1 Acer X203H Service Guide 2 Service Guide Version and Revision Version Release Date Revision History TPV model A00 Nov.-21-2008 Initial Release TARSNDD8Y1ABNN 3 Copyright Copyright © 2003 by Acer Incorporated. All rights reserved. No part of this publication may be reproduced, Transmitted, transcribed, stored in a retrieval system, or translated into any language or computer language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual or otherwise, without the prior written permission of Acer Incorporated. Disclaimer The information in this guide is subject to change without notice. Acer Incorporated makes no representations or warranties, either expressed or implied, with respect to the contents hereof and specifically disclaims any warranties of merchantability or fitness for any particular purpose. Any Acer Incorporated software described in this manual is sold or licensed "as is". Should the programs prove defective following their purchase, the buyer (and not Acer Incorporated, its distributor, or its dealer) assumes the entire cost of all necessary servicing, repair, and any incidental or consequential damages resulting from any defect in the software. Intel is a registered trademark of Intel Corporation. Pentium and Pentium II/III are trademarks of Intel Corporation. Other brand and product names are trademarks and/or registered trademarks of their respective holders. Trademarks Acer is a registered trademark of Acer Incorporated. All other trademarks are property of their respective owners. Conventions The following conventions are used in this manual: Screen messages Denotes actual messages that appear on screen. Note Gives bits and pieces of additional information related to the current topic. Warning Alerts you to any damage that might result from doing or not doing specific actions. Caution Gives precautionary measures to avoid possible hardware or software problems. Important Remind you to do specific actions relevant to the accomplishment of procedures. 4 Preface Before using this information and the product it supports, please read the following general information. 1. This Service Guide provides you with all technical information relating to the BASIC CONFIGURATION decided for Acer's "global" product offering. To better fit local market requirements and enhance product competitiveness, your regional office may have decided to extend the functionality of a machine (e.g. add-on card, modem, or extra memory capability). These LOCALIZED FEATURES will NOT be covered in this generic service guide. In such cases, please contact your regional offices or the responsible personnel/channel to provide you with further technical details. 2. Please note WHEN ORDERING FRU PARTS, that you should check the most up-to-date information available on your regional web or channel. If, for whatever reason, a part number change is made, it will not be noted in the printed Service Guide. For ACER-AUTHORIZED SERVICE PROVIDERS, your Acer office may have a DIFFERENT part number code to those given in the FRU list of this printed Service Guide. You MUST use the list provided by your regional Acer office to order FRU parts for repair and service of customer machines. Warning: (For FCC Certified Models) Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy, and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: 1. Reorient or relocate the receiving antenna. 2. Increase the separation between the equipment and receiver. 3. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. 4. Consult the dealer or an experienced radio/TV technician for help. Notice: 1. The changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. 2. Shielded interface cables and AC power cord, if any, must be used in order to comply with the emission limits. 3. The manufacturer is not responsible for any radio or TV interference caused by unauthorized modification to this equipment. It is the responsibility of the user to correct such interference. As ENERGY STAR® Partner our company has determined that this product meets the ENERGY STAR® guidelines for energy efficiency. Warning: To prevent fire or shock hazard, do not expose the monitor to rain or moisture. Dangerous high voltages are present inside the monitor. Do not open the cabinet. Refer servicing to qualified personnel only. 5 Precautions � Do not use the monitor near water, e.g. near a bathtub, washbowl, kitchen sink, laundry tub, swimming pool or in a wet basement. � Do not place the monitor on an unstable trolley, stand, or table. If the monitor falls, it can injure a person and cause serious damage to the appliance. Use only a trolley or stand recommended by the manufacturer or sold with the monitor. If you mount the monitor on a wall or shelf, uses a mounting kit approved by the manufacturer and follow the kit instructions. � Slots and openings in the back and bottom of the cabinet are provided for ventilation. To ensure reliable operation of the monitor and to protect it from overheating, be sure these openings are not blocked or covered. Do not place the monitor on a bed, sofa, rug, or similar surface. Do not place the monitor near or over a radiator or heat register. Do not place the monitor in a bookcase or cabinet unless proper ventilation is provided. � The monitor should be operated only from the type of power source indicated on the label. If you are not sure of the type of power supplied to your home, consult your dealer or local power company. � The monitor is equipped with a three-pronged grounded plug, a plug with a third (grounding) pin. This plug will fit only into a grounded power outlet as a safety feature. If your outlet does not accommodate the three-wire plug, have an electrician install the correct outlet, or use an adapter to ground the appliance safely. Do not defeat the safety purpose of the grounded plug. � Unplug the unit during a lightning storm or when it will not be used for long periods of time. This will protect the monitor from damage due to power surges. � Do not overload power strips and extension cords. Overloading can result in fire or electric shock. � Never push any object into the slot on the monitor cabinet. It could short circuit parts causing a fire or electric shock. Never spill liquids on the monitor. � Do not attempt to service the monitor yourself; opening or removing covers can expose you to dangerous voltages and other hazards. Please refer all servicing to qualified service personnel � To ensure satisfactory operation, use the monitor only with UL listed computers which have appropriate configured receptacles marked between 100 - 240V AC, Min. 5A. � The wall socket shall be installed near the equipment and shall be easily accessible. Special Notes On LCD Monitors The following symptoms are normal with LCD monitor and do not indicate a problem. Notes � Due to the nature of the fluorescent light, the screen may flicker during initial use. Turn off the Power Switch and then turn it on again to make sure the flicker disappears. � You may find slightly uneven brightness on the screen depending on the desktop pattern you use. � The LCD screen has effective pixels of 99.99% or more. It may include blemishes of 0.01% or less such as a missing pixel or a pixel lit all of the time. � Due to the nature of the LCD screen, an afterimage of the previous screen may remain after switching the image, when the same image is displayed for hours. In this case, the screen is recovered slowly by changing the image or turning off the Power Switch for hours. 6 Table Of Contents Chapter 1 Monitor Features ………………………………………… 7 Introduction ……………………………………… 7 Electrical Requirements ……………………………………… 8 LCD Monitor General Specification ……………………………………… 9 LCD Panel Specification ……………………………………… 10 Factory Preset Timing ……………………………………… 13 Monitor Block Diagram ……………………………………… 14 Main Board Diagram ……………………………………… 15 Software Flow chart ……………………………………… 16 Main Board Layout ……………………………………… 18 Installation ……………………………………… 19 Chapter 2 Operating Instructions ……………………………………… 20 External Controls ……………………………………… 20 Front Panel Controls ……………………………………… 20 eColor Management (OSD) ……………………………………… 21 How to Adjust a Setting ……………………………………… 22 How To Optimize The DOS-Mode ……………………………………… 25 Enter into the factory mode ……………………………………… 25 Chapter 3 Machine Disassembly ……………………………………… 26 Chapter 4 Troubleshooting ……………………………………… 29 Chapter 5 Connector Information ……………………………………… 35 Chapter 6 FRU (Field Replacement Unit) List ……………………………………… 36 Exploded Diagram ……………………………………… 36 Chapter 7 Schematic Diagram ……………………………………… 40 7 Monitor Features Introduction Scope This specification defines the requirements for the 20.0” MICROPROCESSOR based Multi-mode supported high resolution color LCD monitor. This monitor can be directly connected to general 15-pin D-sub VGA connector, also supports VESA DPMS power management and plug & play function. Description The LCD monitor is designed with the latest LCD technology to provide a performance oriented product with no radiation. This will alleviate the growing health concerns. It is also a space saving design, allowing more desktop space, and comparing to the traditional CRT monitor, it consumes less power and gets less weight in addition MTBF target is 50k hours or more. Chart of X203H Panel LTM200KT01 A02(002) SZ SEC Signal Interface D-Sub 15pin Sync Type Separate / Compatible Color Temp User Adjust Support DDC DDC2B Speaker Yes Headphone Jack No Microphone Jack No USB Hub Not support Tilt / Swivel No/No Chapter 1 8 Electrical Requirements Standard Test Conditions All tests shall be performed under the following conditions, unless otherwise specified. Ambient light Dark room (< 1 cd/m2) Viewing distance 40 cm for LCD performance, 20 cm for LCD failures Warm up time ＞30 minutes Analog Input signal 700 mVss Control temperature 6500° K User brightness control The value under user mode User contrast control Set to factory preset value, which allows that the brightest two of 32 linear distributed gray-scales (0～ 700mv) can be distinguished. Picture position and size Factory preset value Viewing angle 90° H and V AC Supply voltage 220V± 5％, 50±3Hz Ambient temperature 20+5℃ Humidity 50% ± 10% Display mode 1600 x 900, 60 Hz, all white e-color mode Set to “User” mode Measurement systems The units of measure stated in this document are listed below: 1 gamma = 1 nano tesla 1 tesla = 10,000 gauss cm = in x 2.54 Lb = kg x 2.2 Degrees F = [°C x 1.8] + 32 Degrees C = [°F - 32]/1.8 u' = 4x/(-2x + 12y + 3) v' = 9y/(-2x + 12y + 3) x = (27u'/4)/[(9u'/2) - 12v' + 9] y = (3v')/[(9u'/2) - 12v' + 9] nits = cd/(m2) = Ft-L x 3.426 lux = foot-candle x 10.76 9 LCD Monitor General Specification LCD Panel Driving system TFT Color LCD Active Display Area 442.8 (W) × 249.075(H) Pixel pitch 0.2768(H) x 0.2768(W) Contrast Ratio 10000 : 1 Max(ACM) Response time 5ms Luminance of White 300(Typ.) cd/㎡ Input Separate Sync. H/V TTL H-Frequency 30kHz – 80kHz V-Frequency 56-75Hz Viewing angle (H)90 (V) 90(Type) Display Colors 16.7M Display mode 1600 x 900 @60Hz EPA ENERGY STAR® ON Mode < 56W OFF Mode < 1W Contrast control Set to factory preset value, which allows that the brightest two of 32 linear distributed gray-scales (0～ 700mv) can be distinguished. Power Source 100 V ~ 240 V，50 ± 3Hz, 60 ± 3Hz Environmental Considerations Operating Temp: 0° to 40°C Storage Temp: -20° to 60°C Operating Humidity: 20% to 85% Peak surge current < 55A peak at 240 VAC and cold starting Power line surge No advance effects (no loss of information or defect) with a maximum of 1 half-wave missing per second 10 LCD Panel Specification General Specifications Block Diagram TFT LCD Module 11 Back light Unit Electrical Characteristics 12 Optical Specifications 13 Factory Preset Timing 460BVESA MODES Horizontal Vertical Mode Resolution Total Nominal Frequency +/- 0.5kHz Sync Polarity Nominal Freq. +/- 1 Hz Sync Polarity Nominal Pixel Clock (MHz) VGA 640x480@60Hz 800 x 525 31.469 N 59.941 N 25.175 640x480@72Hz 832 x 520 37.861 N 72.809 N 31.500 640x480@75Hz 840 x 500 37.500 N 75.000 N 31.500 SVGA 800x600@56Hz 1024 x 625 35.156 P 56.250 P 36.000 800x600@60Hz 1056 x 628 37.879 P 60.317 P 40.000 800x600@72Hz 1040 x 666 48.077 P 72.188 P 50.000 800x600@75Hz 1056 x 625 46.875 P 75.000 P 49.500 XGA 1024x768@60Hz 1344 x 806 48.363 N 60.004 N 65.000 1024x768@70Hz 1328 x 806 56.476 N 70.069 N 75.000 1024x768@75Hz 1312 x 800 60.023 P 75.029 P 78.750 SXGA 1152x864@75Hz 1600x900 67.5 P 75 P 108.000 1280x720@60Hz 1650x750 44.955 P 59.940 P 74.176 1280x960@60Hz 1800x1000 60 P 60 P 108.000 1280x1024@60Hz 1688x1066 63.981 P 60.020 P 108.000 1280x1024@75Hz 1688x1066 79.976 P 75.025 P 135.000 WXGA 1360x768@60Hz 1792x795 47.712 N 60.015 N 85.500 WXGA+ 1600x900@60Hz 2122x934 55.99 P 59.946 N 118.25 1600x900@60Hz 1760x926 55.540 P 59.978 N 97.750 461BIBM MODE DOS 720x400@70Hz 900 x 449 31.469 N 70.087 P 28.322 462BMAC MODES 2BVGA 640x480@67Hz 864 x 525 35.000 N 66.667 N 30.240 SVGA 832x624@75Hz 1152 x 667 49.722 N 74.55 N 57.28 SXGA 1152x 870@75Hz 1568x909 68.700 75.000 100.00 ACER SPECIAL MODE Acer 1280x800@60Hz 1680x831 49.702 P 59.810 N 83.500 14 Monitor Block Diagram The LCD MONITOR will contain a main board, a power board and a key board which house the flat panel control logic, brightness control logic and DDC. The power board will provide AC to DC Inverter voltage to drive the backlight of panel and the main board chips each voltage. Power Board Flat Panel and CCFL backlight Main Board Key board D-SUB Signal CCFL Drive. AC-IN 100V-240V 15 Main Board Diagram Flash Memory PM25LV010A-100SCE (U402) Panel Interface (CN301) Crystal 12MHz (X401) Keypad Interface (CN402) Scalar IC NT68667FG/C (Include MCU, ADC, OSD) (U401) D-Sub Connector (CN101) H sync V sync RGB 16 Software Flow Chart N Y 1 2 N Y 5 Y N 10 Y N 12 Y N 7 Y N 6 4 3 8 9 14 11 13 Y N 15 Y N 16 17 19 Y N 18 17 Remark: 1) MCU initializes. 2) Is the EEPROM blank? 3) Program the EEPROM by default values. 4) Get the PWM value of brightness from EEPROM. 5) Is the power key pressed? 6) Clear all global flags. 7) Are the AUTO and SELECT keys pressed? 8) Enter factory mode. 9) Save the power key status into EEPROM. Turn on the LED and set it to green color. Scalar initializes. 10) In standby mode? 11) Update the lifetime of back light. 12) Check the analog port, are there any signals coming? 13) Does the scalar send out an interrupt request? 14) Wake up the scalar. 15) Are there any signals coming from analog port? 16) Display "No connection Check Signal Cable" message. And go into standby mode after the message disappears. 17) Program the scalar to be able to show the coming mode. 18) Process the OSD display. 19) Read the keyboard. Is the power key pressed? 18 Main Board Layout Symbol Description Symbol Description U401 IC NT68667FG/C QFP-128L CN402 WAFER U703 IC AP1117D33L-13 TO252-3L DIODES CN701 WAFER 9P RIGHT ANELE PITCH U103 IC AZC099-04S SOT23-6L CN301 CONNECTOR U104 IC AZC099-04S SOT23-6L X401 CRYSTAL 12MHz HC-49US ARG6-120 U402 IC PM25LV010A-100SCE SOIC-8 CN101 D-SUB 15PIN VERTICAL CONN WITH SCREW 19 Installation To install the monitor on your host system, please follow the steps below: Steps 20 Operating Instructions Press the power button to turn the monitor on or off. The other control buttons are located at front panel of the monitor. By changing these settings, the picture can be adjusted to your personal preferences. • The power cord should be connected. • Connect the video cable from the monitor to the video card. • Press the power button to turn on the monitor position. The power indicator will light up. External Controls Front panel controls 1. Power Switch: To turn ON or OFF the power. 2. Power LED: Lights up to indicate the power is turned ON. 3. Empowering / Exit: 1) When OSD menu is in active status, this button will act as EXIT-KEY(EXIT OSD menu). 2) When OSD menu is in off status, press this button to select scenario mode. 4. Auto Adjust button / Exit: 1) When OSD menu is in active status, this button will act as EXIT-KEY (EXIT OSD menu). 2) When OSD menu is in off status, press this button for 2 seconds to activate the Auto Adjustment function. The Auto Adjustment function is used to set the HPos, VPos, Clock and Focus. 5. < / > 1) Press < or > to select the desired function. Press < or > to change the settings of the current function. 2) Press < or > to adjust the volume up or down (Only for Audio). 6. MENU / ENTER: Activate OSD menu when OSD is OFF or activate/de-activate adjustment function when OSD is ON. Chapter 2 21 eColor Management (OSD) Operation instructions Step 1: Press “ Key” to open the Acer e-Color Management OSD and access the scenario modes Step 2: Press “<” or “>” to select the mode Step 3: Press “Auto Key ” to confirm the mode and run Auto Adjust 22 How to Adjust a Setting 23 Adjusting the picture 24 25 How To Optimize The DOS-Mode Plug And Play Plug & Play DDC2B Feature This monitor is equipped with VESA DDC2B capabilities according to the VESA DDC STANDARD. It allows the monitor to inform the host system of its identity and, depending on the level of DDC used, communicate additional information about its display capabilities. The DDC2B is a bi-directional data channel based on the I²C protocol. The host can request EDID information over the DDC2B channel. This monitor will appear to be non-functional if there is no video input signal. In order for this monitor to operate properly, there must be a video input signal. This monitor meets the Green monitor standards as set by the Video Electronics Standards Association (VESA) and/or the United States Environmental Protection Agency (EPA) and The Swedish Confederation Employees (NUTEK). This feature is designed to conserve electrical energy by reducing power consumption when there is no video-input signal present. When there is no video input signals this monitor, following a time-out period, will automatically switch to an OFF mode. This reduces the monitor's internal power supply consumption. After the video input signal is restored, full power is restored and the display is automatically redrawn. The appearance is similar to a "Screen Saver" feature except the display is completely off. Pressing a key on the keyboard, or clicking the mouse restores the display. Using the Right Power Cord The accessory power cord for the Northern American region is the wallet plug with NEMA 5-15 style and is UL listed and CSA labeled. The voltage rating for the power cord shall be 125 volts AC. Supplied with units intended for connection to power outlet of personal computer: Please use a cord set consisting of a minimum No. 18 AWG, type SJT or SVT three conductors flexible cord. One end terminates with a grounding type attachment plug, rated 10A, 250V, and CEE-22 male configuration. The other end terminates with a molded-on type connector body, rated 10A, 250V, having standard CEE-22 female configuration. Please note that power supply cord needs to use VDE 0602, 0625, 0821 approval power cord in European counties. Enter into the factory mode: Turn off the power, press the “e-color” and turn the power on. The factory OSD will be at the left top of the panel. 26 Machine Disassembly This chapter contains step-by-step procedures on how to disassemble the monitor for maintenance. The tool for disassembly is as follows: Screwdriver, hexagonal screwdriver, Putty knife. Disassembly Procedure 1. Remove the hinge assembly. 2. Remove the rear cover and bezel. The arrows in blue are the hook that we should put attention to when remove the rear cover. Use plastic putty knife to release hooks, then you can easily remove the rear cover. Chapter 3 27 3． Remove the lamp connectors and remove the screws to remove the panel. Put attention to the LVDS cable. 28 4. Remove the screws to remove the main board and power board. 5. The panel 29 Troubleshooting This chapter provides troubleshooting information for the X203H: 1. No Power Chapter 4 No power Press power key and look if the picture is normal Please reinsert and make sure the AC of 100-240 is normal Reinsert or check the power section Check if X401 oscillate waveforms are normal Measure U703 Pin2=3.3V, OK OK NG NG NG Check U703, C706 and C707 Replace U401 Replace X401 NG OK 30 2. No Picture (LED is orange) No picture The button if under control X401 oscillate waveform is normal Replace U401 Replace X401 Measure U703 Pin2=3.3V, Check Correspondent component Replace U401 X401 oscillate waveform is normal Check U703, C706 and C707 OK OK OK OK OK NG NG NG NG Check reset circuit of U401 is normal Check HS/VS from CN101 is normal Replace X401 Check Correspondent component NG NG OK 31 3. Panel Power Circuit White screen Measure Q302 base is low level? X401 oscillate waveform is normal Check CN301is solder and Q302,Q301 is OK? Check Correspondent component. Replace PANEL Check Correspondent component. Replace U401 OK OK OK Replace X401 OK NG NG NG NG Check reset circuit of U401 is normal 32 4. Key Board OSD is unstable or not working Is Key Pad Board connecting normally? Connect Key Board Is Button Switch normally? Replace Button Switch Y NG NG Is Key Pad Board normally? Replace Key Board Y NG Y Check Main Board 33 5. Power Board 1) No power Check F801 = 14.5V Check AC line volt 110V or 220V Check AC input Check the voltage of C907 (+) Check bridge rectified circuit and F901 circuit Check start voltage for the pin8 of U901 Check R908, R911 and Change U901 NG Check the auxiliary voltage is bigger than 11V and smaller than 25V 1) Check U901 2) Check R913, D904 circuit OK OK NG Check Q901, U902, U903, D901, D902, D906,ZD901,Q904 OK Check U901 pin5 PWM wave OK NG NG NG OK NG Check U901 34 2.) No Backlight Check F801 = 14.5V NG OK Check adapter or MB Check ON/OFF signal Check Interface board NG OK Check U801 PIN12=14.5V NG OK Change Q802, Q804 Check U801 PIN10, 9 have the output of square wave at short time NG OK Change U801 Check Q803, Q812 PIN5, 6, 7, 8 have the output of square wave at short time. NG OK Check Q801, Q803, Q805, Q807, Q812, Q813 Check the output of PT801 Check connecter & lamp OK NG Change PT801 35 Connector Information Chapter 5 36 FRU (Field Replaceable Unit) List This chapter gives you the FRU (Field Replaceable Unit) listing in global configurations of X203H. Refer to this chapter whenever ordering for parts to repair or for RMA (Return Merchandise Authorization). NOTE: Please note WHEN ORDERING FRU PARTS, that you should check the most up-to-date information available on your regional web or channel (http://aicsl.acer.com.tw/spl/). For whatever reasons a part number change is made, it will not be noted in the printed Service Guide. For ACER AUTHORIZED SERVICE PROVIDERS, your Acer office may have a DIFFERENT part number code from those given in the FRU list of this printed Service Guide. You MUST use the local FRU list provided by your regional Acer office to order FRU parts for repair and service of customer machines. NOTE: To scrap or to return the defective parts, you should follow the local government ordinance or regulations on how to dispose it properly, or follow the rules set by your regional Acer office on how to return it. Exploded Diagram (Model: X203H) Chapter 6 37 ITEM PART NO. DESCRIPTION Q`TY 1 BEZEL L20WA-8ACER3-S4 X203H A34G1078 RXA1B0130 1 2 REAR COVER X203H A34G1079 RX 4B0100 1 3 KEY BUTTON Q33G0237 RX 1L0100 1 4 LED LENS A33G0270 1 1L0100 1 5 MAINFRAME A15G0492101401 1 6 SHIELD A85G0135101 1 7 HINGE COVER L A33G0271 RX 1L0200 1 8 HINGE COVER R A33G0271 RX 2L0200 1 9 STAND FRONT A34G0473 RX 1B0100 1 10 STAND REAR A34G0474 RX 1B0100 1 11 BASE A34G0475 RX 1B0130 1 12 HINGE A37G0050 2 1 13 BASE BKT A15G0263201 1 14 RUBER FOOT-1 A12G0006 1 1 15 RUBER FOOT-2 A12G0007 1 2 16 BASE BUTTON A33G0266 RX 1L0100 1 S1 SCREW 0M1G1730 6120 4 S2 SCREW 0M1G 130 6120 2 S3 SCREW 0Q1G 140 10120 6 S4 SCREW 0M1G 140 8125 4 S5 SCREW 0Q1G 130 8120 8 38 Part List Above picture show the description of the following component. Picture Description Part No. Main Frame A15G0492101401 Bezel A34G1078 RXA1B0130 Panel 750GLS200KT112N000 Power Board PWPC8A41EQI3 39 Main Board CBPCRNDABQN Key Board KEPC7QK1 Stand Front A34G0473 RX 1B0100 Base A34G0475 RX 1B0130 Stand Rear A34G0474 RX 1B0100 Hinge A37G0050 2 40 Schematic Diagram Main Board 1 6 2 7 3 8 4 9 5 11 12 13 14 15 10 17 16 CN101 DB15 DSUB_5V ESD_5V 5VCC R102 100R 1/10W 5% VGA_R- DSUB_B+ I/O1 1 GND 2 I/O2 3 I/O3 4 VDD 5 I/O4 6 U104 AZC099-04S DSUB_SCL DSUB_SDA E5VCC C101 NC VGA_B+ VGA_R+ VGA_G+ I/O1 1 GND 2 I/O2 3 I/O3 4 VDD 5 I/O4 6 U103 AZC099-04S V_Sy nc VGA_G- H_Sy nc H_Sy nc R141 1K 1/16W 5% VGA_DET DSUB_B- DSUB_SOG DSUB_G+ DSUB_G- DSUB_R+ DSUB_R- DSUB_H DSUB_V DDC1_SCL R143 4K7 1/16W 5% R144 4K7 1/16W 5% DDC1_SDA DSUB_SCL VGA_B- DSUB_SDA OEM MODEL Size Rev Date Sheet of TPV MODEL PCB NAME 称 爹 T P V ( Top Victory Electronics Co . , Ltd. ) Key Component 絬 隔 瓜 絪 腹 Acer X203H Analog only 1 Acer B 2 5 Wednesday , Nov ember 19, 2008 <称爹> 2.0.Input G3108-1-X-X-17-081119 Modify in 2008/01/28 候綼　U101 R104 1K 1/16W 5% C113 5pF/50V V_Sy nc DSUB_5V ZD105 RLZ5.6B 1 2 FB102 BEAD 5V_ESD 5V_ESD 5V_ESD VGA_R+ 1 2 FB105 120 OHM VGA_B+ VGA_PLUG VGA_G- C107 1000pF R142 1K 1/16W 5% R111 100R 1/16W 5% R101 100R 1/16W 5% C114 0.047uF R112 75R 1/16W 5% VGA_G+ C106 0.047uF VGA_R- C103 22pF C104 22pF ZD104 RLZ5.6B C110 0.047uF VGA_B- R103 1K 1/16W 5% 1 2 FB103 BEAD R105 100R 1/16W 5% 候綼　U103 C111 0.047uF VGA_G+ R108 75R 1/16W 5% VGA_B+ Modify in 2008/03/07 R115 100R 1/16W 5% R117 100R 1/16W 5% R110 470R 1/16W 5% C109 5pF/50V R116 75R 1/16W 5% R106 2K2 1/16W 5% C108 0.047uF VGA_R+ R109 100R 1/16W 5% C112 NC R107 2K2 1/16W 5% C102 0.047uF 1 2 FB101 BEAD R113 100R 1/16W 5% R114 100R 1/16W 5% C105 5pF/50V Chapter 7 41 +5V + C305 100uF25V R304 47K 1/16W 5% R303 10K 1/16W 5% C302 0.1uF/16V PANEL_VCC T0M T0P T1P T1M T2M T2P TCLK1P TCLK1M T3M T3P T4P T4M T5P T5M R301 330 OHM 1/4W T6M T6P TCLK2P T7P T7M TCLK2M PPWR_ON# C301 0.1uF/16V Q301 AO3401 R305 0 OHM +-5% 1/8W PANEL_VCC Q302 2N3904S-RTK/PS R306 10K 1/16W 5% 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 CN301 CONN AO3401L 2 1 C304 NC C303 NC C306 0.1uF 16V S D 3 G R307 47K 1/16W 5% OEM MODEL Size Rev Date Sheet of TPV MODEL PCB NAME 称 爹 T P V ( Top Victory Electronics Co . , Ltd. ) Key Component 絬 隔 瓜 絪 腹 Acer X203H Analog only 1 Acer A 3 5 Wednesday , Nov ember 19, 2008 <称爹> 3.0.OUTPUT G3108-1-X-X-17-081119 42 DSUB_5V C711 NC/0.1uF/16V D701 SM340A 3 1 2 D702 BAT54C 1 2 FB701 300 OHM E5VCC ADJ 1 Vout 2 Vin 3 U702 NC/AIC1117A-18PE 5VCC R710 NC C710 NC R707 NC R703 NC PANEL_ID# C703 NC VCC3.3 VCC3.3 R701 NC VCC3.3 NT60670B OPTION + C704 NC/100uF25V lock type 5VCC Both 223 and 252 foot-print on_BACKLIGHT BKLT-EN BKLT-VBRI +5V BKLT-VBRI +5V adj_BACKLIGHT R702 10K 1/16W 5% + C706 100uF25V C701 NC C708 0.1uF/16V C702 NC 1 2 3 4 5 6 7 8 9 CN701 CONN R705 10K 1/16W 5% R704 4K7 1/16W 5% BKLT-EN + C707 100uF25V C709 0.1uF/16V R706 1K 1/16W 5% VSS 1 VOUT 2 VIN 3 U701 NC/AP1117E33LA Q701 2N3904S-RTK/PS C705 NC/0.1uF/16V VCC1.8 Volume# Mute ADJ(GND) 1 VOUT 2 VIN 3 U703 AP1117D33LA OEM MODEL Size Rev Date Sheet of TPV MODEL PCB NAME 称 爹 T P V ( Top Victory Electronics Co . , Ltd. ) Key Component 絬 隔 瓜 絪 腹 Acer X203H Analog only 1 Acer B 4 5 Wednesday , Nov ember 19, 2008 <称爹> 4.0.POWER G3108-1-X-X-17-081119 5VCC +5V 5VCC DVI_5V 43 EE_WP T0M T0P T1M T1P T2P T2M T3M T3P TCLK1P TCLK1M T4M T6M T4P T7P T5P TCLK2M T6P T7M TCLK2P T5M MUTE R454 NC SPI_SI SPI_CK CN402 PIN 5~7㎝CN403 PIN1~3　LAY R467 NC/0R05 1/16W +5V R465 NC/10K 1/16W C413 0.1uF/16V NC 1 NC 2 NC 3 VSS 4 SDA 5 SCL 6 WC 7 VCC 8 U403 NC/M24C16 C430 0.1uF/16V FB404 300OHM C412 0.1uF/16V R472 75R 1/16W 5% +5V R469 2K2 1/16W 5% R470 0R05 1/8W R471 NC C438 4.7uF/16V 1 2 3 Q402 2N3906S-RTK/PS R468 NC/0R05 1/16W LED_LF_BLUE C442 0.1uF/16V LED_B LED_A AVCC CN401 PIN1~5㎝CN406 PIN1~5 　LAY FFC CONNECTOR 1 2 3 4 5 6 7 8 CN401 NC/2x4PIN/1.0mm DUBUG DSUB_R+ FB407 300OHM C447 0.1uF/16V R411 10K 1/16W 5% AVCC R408 10K 1/16W 5% KEY_RIGHT LED_ORANGE DVDD MSCL R417 100R 1/16W 5% R418 120R 1/16W 5% R445 NC/0R05 1/16W R421 NC/120R 1/8W R422 NC/120R 1/8W R446 NC/0R05 1/16W LED_LF_BLUE C423 0.1uF/16V RSTB 1 DVDD 2 DGND 3 RX2+ 4 RX2- 5 AVCC 6 RX1+ 7 RX1- 8 AGND 9 RX0+ 10 RX0- 11 AGND 12 RXC+ 13 RXC- 14 AVCC 15 REXT 16 PVCC 17 PGND 18 BIN1+ 19 BIN1- 20 SOG1I 21 GIN1+ 22 GIN1- 23 RIN1+ 24 RIN1- 25 ADC_VAA 26 ADC_GNDA 27 PC2 28 PD6 29 PB3/ADC3/INTE1 30 P31/TXD 31 P30/RXD 32 PB2/ADC2/INTE0 33 PB7/DDC_SDA1* 34 PB6/DDC_SCL1* 35 PA3/PWM5 36 PA4/PWM6* 37 PA5/PWM7* 38 PA6/PWM8* 39 PA7/PWM9* 40 HSYNCI1 41 VSYNCI1 42 PLL_GND 43 GND 44 PLL_VDD 45 PB5/DVI_SDA0* 46 PB4/DVI_SCL0* 47 PD5 48 P35 49 P34 50 DVDD 51 CVDD 52 DVDD 53 RSBA1P/V0 54 RSBA1M/V1 55 RSBA2P/V2 56 RSBA2M/V3 57 RSBA3P/V4 58 RSBA3M/V5 59 RSCLKAP/V6 60 RSCLKAM/V7 61 RSGA1P/VCKI 62 DGND/CGND 63 DGND/CGND 64 PC6 102 DGND/CGND 101 DGND/CGND 100 DGND/CGND 99 DGND/CGND 98 DGND/CGND 97 DGND/CGND 96 DGND/CGND 95 DGND/CGND 94 DGND/CGND 93 DGND/CGND 92 DGND/CGND 91 DVDD 90 DGND/CGND 89 RSGB1M/T0M 88 RSGB1P/T0P 87 RSCLKBM/T1M 86 RSCLKBP/T1P 85 RSBB3M/T2M 84 RSBB3P/T2P 83 RSBB2M/TCLK1M 82 RSBB2P/TCLK1P 81 RSBB1M/T3M 80 RSBB1P/T3P 79 DGND/CGND 78 RSRA3M/T4M/RSRB0M 77 RSRA3P/T4P/RSRB0P 76 RSRA2M/T5M/GSGB0M 75 RSRA2P/T5P/RSGB0P 74 RSRA1M/T6M/RSGB0M 73 RSRA1P/T6P/RSBB0P 72 RSGA3M/TCLK2M 71 RSGA3P/TCLK2P 70 RSGA2M/T7M 69 RSGA2P/T7P 68 PA1/PWM3 67 PA2/PWM4 66 PA0/PWM2 65 OSCO 128 OSCI 127 PB0/ADC0 126 PB1/ADC1 125 PC5 124 PC4/PWM1 123 PC3/PWM0 122 PC1* 121 PC0* 120 CVDD 119 PWMB*/GPO8 118 PWMA*/GPO7 117 NC 116 CVDD 115 INT_HSO/GPO5 114 INT_VSO/GPO4 113 GPO3/AD1 112 GPO2/AD0 111 NC 110 GND 109 PD4 108 SPI_CLK 107 SPI_SI 106 SPI_SO 105 SPI_CE 104 PC7 103 U401 NT68667FG/C PANEL_ID# R431 NC/100R 1/16W 5% R429 NC/100R 1/16W 5% VSO HSO LED_ORANGE KEY2 FB406 300OHM C448 0.1uF/16V R401 470 OHM +-1% 1/16W VSO C434 0.1uF/16V LED_A MSCL SPI_SO R414 10K 1/16W 5% ADC_VAA LED_B FB403 300OHM HSO CVDD PVCC C410 0.1uF/16V C411 NC/0.22uF16V C422 0.1uF/16V C431 0.1uF/16V R420 10K 1/8W 5% LED_GRN/BLUE R439 NC VCC3.3 KEY1 C435 0.1uF/16V KEY2 R462 1M 1/16W 5% SPI_CE CE 1 SO 2 WP# 3 GND 4 SI 5 SCK 6 HOLD# 7 VCC 8 U402 SST25VF010A-33-4C-SAE SOIC-8 BY SST 1 2 3 4 5 CN406 NC/CONN KEY_LEFT MSDA KEY_AUTO R419 120R 1/8W 5% CVDD KEY1 MSDA R409 100R 1/16W 5% C401 0.22uF16V ADC_VAA C432 0.1uF/16V 1 2 3 4 5 6 7 CN402 CONN VGA_DET POWER_KEY# POWER_KEY# C433 0.1uF/16V R436 NC/0R05 1/16W R438 NC AVCC PVCC R466 NC/120R 1/8W LED_LF_BLUE Modify in 2008/03/07 C436 NC C440 1uF 16V 1 2 3 CN403 NC/CONN R443 3.9K OHM 1% 1/16W DDC2_SCL DVDD DVI_DET 1 2 3 4 CN405 NC/CONN +5V C439 1uF 16V WP DVDD R425 1K 1/16W 5% 5V_DET DVDD 5V_DET EE_WP R440 NC/4K7 1/16W 5% R415 1K 1/16W 5% R416 1K 1/16W 5% TX R412 NC/100R 1/16W 5% R441 NC/4K7 1/16W 5% R405 10K 1/16W 5% R437 NC KEY2 KEY1 DVDD R444 3.9K OHM 1% 1/16W DSUB_G+ DSUB_G- DSUB_R- DSUB_SOG DSUB_B+ DSUB_B- DSUB_V DSUB_H POWER_KEY# DDC1_SDA DDC1_SCL RX2P RX2N RX1P RX1N ZD403 RLZ5.6B ZD401 RLZ5.6B LED_GRN/BLUE LED_GRN/BLUE LED_ORANGE ZD402 NC RX0P RX0N RXCN RXCP DDC2_SDA NT68667FG/C SPI_CE R402 NC/100R 1/16W 5% SPI_SO SPI_SI SPI_CK WP HDCP_CTRL DDC_WP on_BACKLIGHT adj_BACKLIGHT Volume# OEM MODEL Size Rev Date Sheet of TPV MODEL PCB NAME 称 爹 T P V ( Top Victory Electronics Co . , Ltd. ) Key Component 絬 隔 瓜 絪 腹 Acer B/V203H Analog only 1 Acer C 5 5 Wednesday , Nov ember 19, 2008 <称爹> 5.0.SCALER G3108-1-X-X-5-080818 C407 0.1uF/16V C420 22pF R403 10K 1/16W 5% C446 0.1uF/16V R407 20K OHM 1/16W Q401 NC/2N3906S-RTK/PS C404 0.1uF/16V C421 22pF C406 0.1uF/16V FB401 300OHM C403 0.1uF/16V PPWR_ON# 1 2 X401 12MHz VCC3.3 VCC1.8 TX R406 NC/120R 1/8W +5V 44 Power board R920 1K 1/10W 1% MUTE VOL R935 NC 1 2 ZD901 MTZJ T-72 16B 1 2 FB902 BEAD + C931 NC R911 10K OHM 1/4W +-5% ! C909 NC/0.22uF/275V ! ON/OFF +5V 1 2 3 4 5 6 7 8 9 CN902 Wire Harness OEM MODEL Size Rev Date Sheet of TPV MODEL PCB NAME 称 爹 T P V ( Top Victory Electronics Co . , Ltd. ) Key Component 絬 隔 瓜 絪 腹 PWPC8A41EQI3 1 Custom 1 3 Wednesday , Nov ember 12, 2008 715G2892-1A ODM MODEL 01.POWER G2892-1A-X-X-14-081112 DIM Q904 KTD1028 +5V F901 FUSE F902 FUSE D905 NC/31DQ06FC3 R901 620K OHM 1/4W + C920 1000uF25V + C922 470UF M 16V 2 1 3 4 - + BD901 KBP208G 1 2 3 D906 MBRF1060CT R929 100 OHM 1/4W R900 620K OHM 1/4W R907 1K 1/10W 1% R928 1K 1/10W 1% C903 1000PF/250VAC R910 100 OHM 1/4W +5V1 + C907 ! C902 1000PF/250VAC F903 NC R903 100 OHM 1/4W + C921 NC/1000uF25V 1 2 3 CN901 SOCKET C917 0.001uF R909 100 OHM 1/4W R930 100 OHM 1/4W NR901 NTCR R905 470R 1/10W 5% C916 0.001uF R919 150R 1/8W 5% C923 0.001uF R902 620K OHM 1/4W 1 2 4 3 U902 PC123X2YFZOF C908 0.47UF 1 4 2 3 L901 30mH R912 100 OHM 1/4W U903 KIA431A-AT/P +14.5V C900 3300pF 250V F801 0R05 1/4W 5% 1 2 HS1 HEAT SINK(Q901) 1 2 HS3 HEAT SINK(D906_5V/2.5A) 1 2 FB901 BEAD C912 0.1uF/25V + C913 22uF/50V R913 5.1 OHM 1/4W +-5% R917 10R 1/4W 5% ! C915 C914 470pF 1 2 GND1 GND C911 1500PF2KV D904 FR103 6 8 5 2 1 11 10 12 9 7 4 T901 POWER X'FMR N.C. D903 FR107 + C925 1000uF M 16V R906 100K OMH 2W +-5% R924 0.39 OHM 2W +-5% + C918 1000uF35V R904 100OHM 2W ! ! ! ! ! L907 R918 10K 1/10W 1% C926 0.1uF/16V D907 IN4148 ! R931 NC R932 NC R933 NC R934 NC ! ! D908 NC/IN4148 1 2 HS4 NC 0 R921 NC L906 N.C. R923 220 OHM 1/4W CT 1 COMP 2 CS 3 GND 4 OUT 5 VCC 6 NC 7 HV 8 U901 LD7576 2 1 3 Q901 STP9NK65ZFP R914 43.2K OHM 1% 1/4W ! R908 10K OHM 1/4W +-5% ! 1 2 D901 SR5150 R916 3.65K OHM 1% 1/10W R925 2.43K OHM 1% 1/10W 1 2 D902 SR5150 C927 0.047uF 1 2 HS2 NC/HEAT SINK(D906_5V/4A) C924 0.1uF/16V 45 C811 0.1uF/25V C803 C815 C816 Q810 MMBT3904 OEM MODEL Size Rev Date Sheet of TPV MODEL PCB NAME 称 爹 T P V ( Top Victory Electronics Co . , Ltd. ) Key Component 絬 隔 瓜 絪 腹 PWPC8A41EQI3 1 Custom 2 3 Wednesday , Nov ember 12, 2008 715G2892-1A ODM MODEL 02.INVERTER G2892-1A-X-X-14-081112 R822 27K 1/10W 1% R817 2.43K OHM 1% 1/10W R834 47K 1/10W 5% R810 1K 1/10W 1% +14.5V C813 1N 100V NPO +/-5% R818 10K 1/10W 1% R814 68K 1/10W 5% Q804 PDTC144WK F801 0 OHM 1/4W D804 IN4148 R802 1K 1/10W 1% R819 470K 1/10W 5% R836 33 OHM 1/4W R843 0R05 1/10W R837 33 OHM 1/4W R811 10R 1/10W 5% + C802 470UF/25V R804 1K 1/10W 1% Q809 MMBT3904 R823 10K 1/10W 1% R825 10K 1/10W 1% R832 10K 1/10W 1% R835 10K 1/10W 1% R813 1K 1/10W 1% C817 2.2uF/10V R808 1K 1/10W 1% R828 18K 1/8W 1% R827 2.43K OHM 1% 1/10W DIM ON/OFF Q808 MMBT3904 C807 Q802 PDTA144WK R807 10K 1/10W 1% R838 33R 1/10W 5% R839 33R 1/10W 5% R806 10K 1/10W 1% 3 1 2 D803 BAV70 C810 2.2uF/10V Q801 MMBT3904 C806 0.1uF/25V Q811 RK7002 1 2 CN804 CONN C812 R803 10R 1/10W 5% 3 1 2 D802 BAV70 Q813 MMBT3904 1IN+ 1 1IN- 2 FEEDBACK 3 DTC 4 CT 5 RT 6 GND 7 C1 8 E1 9 E2 10 C2 11 VCC 12 OUTPUT CTRL 13 REF 14 2IN- 15 2IN+ 16 U801 TL494IDR 1 2 3 Q805 MMBT2907AK OLP1 OLP4 OLP2 OLP3 +14.5V R820 18K 1/10W 1% OLP1 OLP2 OLP3 OLP4 1 2 3 Q807 MMBT2907AK R841 1.5K 1/10W 1% +14.5V R831 10K 1/10W 1% R821 NC C804 NC/5pF/3KV R842 1.5K 1/10W 1% 1 2 CN803 CONN 3 1 2 D801 BAV70 R826 47K 1/10W 1% 1 2 3 4 5 6 7 8 PT801 POWER X'FMR C 3 B 1 E 2 D805 BAW56 R824 68K 1/10W 5% Q806 RK7002 R812 2.43K OHM 1% 1/10W S1 1 G1 2 S2 3 G2 4 D1 8 D1 7 D2 6 D2 5 Q803 P8008HV 1 2 CN801 CONN R815 68K 1/10W 5% R816 30K OHM 1/4W S1 1 G1 2 S2 3 G2 4 D1 8 D1 7 D2 6 D2 5 Q812 P8008HV C809 680pF 1 2 CN802 CONN R801 2.43K OHM 1% 1/10W R809 2.43K OHM 1% 1/10W C801 NC/5pF/3KV R833 NC R840 10K 1/10W 1% C808 0.022uF 46 1 2 HS4 NC R612 NC R601 NC C613 NC MUTE +5V1 R610 NC Lin 1 2 3 4 CN602 NC SHUTDOWN 1 BYPASS 2 RIN- 3 GND 4 GND 5 LIN- 6 VOLUME 7 SE/BTL 8 LOUT- 9 VDD 10 LOUT+ 11 GND 12 GND 13 ROUT+ 14 VDD 15 ROUT- 16 U601 NC R603 NC Rin Q608 NC C612 NC R609 NC OEM MODEL Size Rev Date Sheet of TPV MODEL PCB NAME 称 爹 T P V ( Top Victory Electronics Co . , Ltd. ) Key Component 絬 隔 瓜 絪 腹 PWPC8A41EQI3 1 A 1 3 Wednesday , Nov ember 12, 2008 715G2892-1A ODM MODEL 04.AUDIO G2892-1A-X-X-14-081112 ROUT- LOUT- ROUT+ R608 R R606 NC 1 2 FB602 NC C606 NC C610 NC R605 NC R607 NC + C604 NC C601 NC C609 NC C603 NC C611 NC R602 NC C602 NC C608 NC R604 NC +5V1 1 2 3 5 4 CN601 NC +5V1 +5V1 LOUT+ VOL 1 2 3 4 CN603 NC 47 Key board GND R002 2K OHM 1% 1/10W AUTO LBADC1 VOL- (2K) POWER MENU (2K) (GND) (1K) LBADC2 VOL+ 0 V AUTO LBADC1 R004 2K OHM 1% 1/10W LBADC2 MENU LED_GRN# LED_RED# change Net name MENU--->AUTO AUTO----MENU DC_POWERON 1 2 3 4 5 6 CN001 CONN 2007/5/11 1 2 4 3 5 SW006 SW 1 2 4 3 5 SW003 SW G 1 GND1 GND-EMI G 1 GND2 GND-EMI GND 1 2 4 3 5 SW004 SW 1 2 4 3 5 SW001 SW ECOLOR ZD005 UDZS5.6B 1 2 4 3 5 SW002 SW 2007/5/18 2007/5/18 2007/5/18 2007/5/18 2007/5/18 2007/5/18 CONNECTOR 1 2 4 3 5 SW005 SW C006 NC VOL+ C005 NC C002 NC C008 NC C003 NC ZD002 UDZS5.6B 2007/5/18 C001 NC C004 NC 1.1V 1.1V 0.65V LED POWER AUTO MENU VOL- VOL+ C010 NC ZD001 UDZS5.6B CN001 ZD006 UDZS5.6B C011 NC C009 NC ECOLOR GND 2007/5/18 C007 NC ZD004 UDZS5.6B R005 1K 1/10W 1% OEM MODEL Size Rev Date Sheet of TPV MODEL PCB NAME 称 爹 T P V ( Top Victory Electronics Co . , Ltd. ) Key Component 絬 隔 瓜 絪 腹 ACER A X173/X173W/X193W/P193W/X223W B 1 2 Sunday , June 17, 2007 715G2731-B-AC <称爹> 02.Key Board G2731-B-AC-X-1-070617 LED_RED# c 1 A1 2 A2 3 LED001 LED ZD003 UDZS5.6B ECOLOR(GND) VOL- GND 0 V LED_GRN#
