MEDIA CONTROLLER YMC-700/YMC-500 IMPORTANT NOTICE This manual has been provided for the use of authorized YAMAHA Retailers and their service personnel. It has been assumed that basic service procedures inherent to the industry, and more specifi cally YAMAHA Products, are already known and understood by the users, and have therefore not been restated. WARNING: Failure to follow appropriate service and safety procedures when servicing this product may result in personal injury, destruction of expensive components, and failure of the product to perform as specifi ed. For these reasons, we advise all YAMAHA product owners that any service required should be performed by an authorized YAMAHA Retailer or the appointed service representative. IMPORTANT: The presentation or sale of this manual to any individual or fi rm does not constitute authorization, certifi cation or recognition of any applicable technical capabilities, or establish a principle-agent relationship of any form. The data provided is believed to be accurate and applicable to the unit(s) indicated on the cover. The research, engineering, and service departments of YAMAHA are continually striving to improve YAMAHA products. Modifications are, therefore, inevitable and specifi cations are subject to change without notice or obligation to retrofi t. Should any discrepancy appear to exist, please contact the distributor's Service Division. WARNING: Static discharges can destroy expensive components. Discharge any static electricity your body may have accumulated by grounding yourself to the ground buss in the unit (heavy gauge black wires connect to this buss). IMPORTANT: Turn the unit OFF during disassembly and part replacement. Recheck all work before you apply power to the unit. 1 0 1 1 3 6 animate '09.06 P.O.Box 1, Hamamatsu, Japan Copyright © 2009 All rights reserved. This manual is copyrighted by YAMAHA and may not be copied or redistributed either in print or electronically without permission. SERVICE MANUAL ■ CONTENTS TO SERVICE PERSONNEL ............................................2 FRONT PANELS .........................................................3–4 REAR PANELS ...........................................................5–6 REMOTE CONTROL PANEL ..........................................7 SPECIFICATIONS ..................................................... 7–11 INTERNAL VIEW ..........................................................12 DISASSEMBLY PROCEDURES ............................. 13–17 UPDATING FIRMWARE ..........................................18–21 SELF-DIAGNOSTIC FUNCTION ...........................22–48 IC DATA ...................................................................49–61 PIN CONNECTION DIAGRAMS .............................62–64 BLOCK DIAGRAMS ................................................66–67 PRINTED CIRCUIT BOARDS ................................. 68–74 SCHEMATIC DIAGRAMS .......................................75–89 REPLACEMENT PARTS LIST ................................91–99 REMOTE CONTROL ...................................................100 YMC-700/YMC-500 For U model www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 2 YMC-700/YMC-500 YMC-700/YMC-500 This product contains chemicals known to the State of California to cause cancer, or birth defects or other reproductive harm. DO NOT PLACE SOLDER, ELECTRICAL/ELECTRONIC OR PLASTIC COMPONENTS IN YOUR MOUTH FOR ANY REASON WHATSOEVER! Avoid prolonged, unprotected contact between solder and your skin! When soldering, do not inhale solder fumes or expose eyes to solder/flux vapor! If you come in contact with solder or components located inside the enclosure of this product, wash your hands before handling food. 1. Critical Components Information Components having special characteristics are marked ⚠ and must be replaced with parts having specifications equal to those originally installed. 2. Leakage Current Measurement (For 120V Models Only) When service has been completed, it is imperative to verify that all exposed conductive surfaces are properly insulated from supply circuits. • Meter impedance should be equivalent to 1500 ohms shunted by 0.15 μF. For U model “CAUTION” “F1: FOR CONTINUED PROTECTION AGAINST RISK OF FIRE, REPLACE ONLY WITH SAME TYPE 5A, 125V FUSE.” For C model CAUTION F1: REPLACE WITH SAME TYPE 5A, 125V FUSE. ATTENTION F1: UTILISER UN FUSIBLE DE RECHANGE DE MÉME TYPE DE 5A, 125V. All of the P.C.B.s installed in this unit and solder joints are soldered using the lead free solder. Among some types of lead free solder currently available, it is recommended to use one of the following types for the repair work. • Sn + Ag + Cu (tin + silver + copper) • Sn + Cu (tin + copper) • Sn + Zn + Bi (tin + zinc + bismuth) Caution: As the melting point temperature of the lead free solder is about 30°C to 40°C (50°F to 70°F) higher than that of the lead solder, be sure to use a soldering iron suitable to each solder. ■ TO SERVICE PERSONNEL • Leakage current must not exceed 0.5mA. • Be sure to test for leakage with the AC plug in both polarities. WARNING: CHEMICAL CONTENT NOTICE! About lead free solder WALL OUTLET EQUIPMENT UNDER TEST AC LEAKAGE TESTER OR EQUIVALENT INSULATING TABLE www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 3 YMC-700/YMC-500 YMC-700/YMC-500 YMC-700 Top view Side view POWER indicators Front view ■ FRONT PANELS www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 4 YMC-700/YMC-500 YMC-700/YMC-500 YMC-500 Top view Side view POWER indicators Front view www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 5 YMC-700/YMC-500 YMC-700/YMC-500 YMC-700 Rear view Bottom view ■ REAR PANELS www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 6 YMC-700/YMC-500 YMC-700/YMC-500 YMC-500 Rear view Bottom view www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 7 YMC-700/YMC-500 YMC-700/YMC-500 ■ SPECIFICATIONS ■ Audio Section Minimum RMS Output Power (Power Amp. Section) (1 kHz, 0.7 % THD, 6 ohms) FRONT L/R, CENTER, SURROUND L/R .......................................................................................... 50 W/ch MAX. Power Per Channel (1 kHz, 10 % THD, 6 ohms) FRONT L/R, CENTER, SURROUND L/R .......................................................................................... 55 W/ch Dynamic Power Per Channel (IHF) FRONT L/R drive 8 / 6 / 4 / 2 ohms ............................................. 40 / 50 / 70 / 110 W Dynamic Headroom 6 ohms .......................................................................................0 dB Input Sensitivity/Input Impedance (1 kHz, 50 W/6 ohms) Analog input [AUDIO IN ③] ............................... 0.45 V / 47 k-ohms Maximum Input Signal (1 kHz, 0.5 % THD) Analog input [AUDIO IN ③] ........................................2.4 V or more Output Level/Output Impedance SUBWOOFER ........................................................ 2.4 V/1.2 k-ohms Frequency Response (20 Hz to 20 kHz) Analog, FRONT ......................................................................0/-3 dB Total Harmonic Distortion (1 kHz, 25 W/6 ohms) ....................................................................................0.05 % or less Signal to Noise Ratio (IHF-A network) Digital (Input to SP OUT) ........................................... 98 dB or more Analog (Input to SP OUT) .......................................... 82 dB or more Residual Noise (IHF-A Network) FRONT L/R to SP OUT ................................................150 μV or less Channel Separation (1 kHz / 10 kHz) Analog (Input 5.1 k-ohms shorted) ....................................................... 60 dB or more / 45 dB or more Volume Control ......................................... MUTE / -80 dB to +16.5 dB / 0.5 dB step Tone Control Characteristics Bass Boost/Cut ..................................................................±6 dB, 20 Hz Treble Boost/Cut ................................................................ ±6 dB, 20 kHz Filter Characteristics FRONT, CENTER, SURROUND small (H.P.F.) ................................fc=40/60/80/100/120/160/200 Hz, 12 dB/oct. SUBWOOFER small (L.P.F.) ................................fc=40/60/80/100/120/160/200 Hz, 24 dB/oct. ■ Video Section Composite Video Signal Level ...............................................................................1 Vp-p / 75 ohms Component Video Signal Level Y .............................................................................1 Vp-p / 75 ohms Pb/Pr ...................................................................0.7 Vp-p / 75 ohms Video Maximum Input Level ............................................................................... 1.5 Vp-p or more Frequency Response Component video signal level .......................5 Hz to 60 MHz, -3 dB ■ FM Section Tuning Range .............................................................................87.5 to 107.9 MHz Signal to Noise Ratio (IHF) Mono ........................................................................................73 dB Stereo ......................................................................................70 dB YMC-700 YMC-500 Top view Bottom view ■ REMOTE CONTROL PANEL RAV35 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 8 YMC-700/YMC-500 YMC-700/YMC-500 Harmonic Distortion (1 kHz) Mono ........................................................................................ 0.5 % Stereo ...................................................................................... 0.5 % Antenna Input ....................................................................... 75 ohms unbalanced ■ General Power Supply ................................................................................ AC 120 V, 60 Hz Power Consumption [YMC-700] ............................................................................................... 60 W [YMC-500] ............................................................................................... 50 W Standby Power Consumption (reference data) ................................................................................................. 0.6 W Maximum Power Consumption (5 ch drive, 10 % THD) ............................................................ 170 W Dimensions (W x H x D) [YMC-700] .............................. 298 x 93 x 332 mm (11-3/4" x 3-5/8" x 13-1/8") [YMC-500] .............................. 298 x 93 x 313 mm (11-3/4" x 3-5/8" x 12-3/8") Weight ................................................................................. 3.6 kg (7.9 lbs.) Finish [YMC-700] ..................................................................................... Black color Silver color [YMC-500] ..................................................................................... Black color Silver color Accessories Remote control ..............................................................................x 1 Battery (R03, AAA, UM-4) .............................................................x 2 IR flasher (3.0 m) ..........................................................................x 2 Indoor FM antenna (1.4 m) ...........................................................x 1 Optimizer microphone (6.0 m) .......................................................x 1 Power cable (2.0 m) .....................................................................x 1 * Specifications are subject to change without notice due to product improvements. U ........................U.S.A. model Manufactured under license from Dolby Laboratories. Dolby, Pro Logic and the double-D symbol are trademarks of Dolby Laboratories. DTS and DTS Digital Surround are registered trademarks and the DTS logos, Symbol and DTS 96/24 are trademarks of DTS, Inc. © 1996-2008 DTS, Inc. All Rights Reserved. “iPod” is a trademark of Apple Inc., registered in the U.S. and other countries. MPEG Layer-3 audio coding technology licensed from Fraunhofer IIS and Thomson. “HDMI”, the “HDMI” logo and “High-Definition Multimedia Interface” are trademarks, or registered trademarks of HDMI Licensing LLC. “x.v.Color” is a trademark of Sony Corporation. Rhapsody and the Rhapsody logo are registered trademarks of RealNetworks, Inc. The Wi-Fi CERTIFIED Logo is a certification mark of the Wi-Fi Alliance. Windows XP, Windows Vista, Windows Media Audio, Windows Media Connect and Windows Media Player are either registered trademarks or trademarks of Microsoft corporation in the United States and/or other countries. This product is manufactured under license from Allegro Software Development Corporation. ©1996-2008 Allegro Software Development Corporation. All rights reserved. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 9 YMC-700/YMC-500 YMC-700/YMC-500 Unit: mm (inch) Unit: mm (inch) • DIMENSIONS YMC-700 YMC-500 93 (3-5/8") 300 (11-7/8") 233 (9-1/8") 332 (13-1/8") 47 (1-7/8") 97 (3-13/16") 13 (1/2") 19 (3/4") 298 (11-3/4") 248 (9-3/4") Front view Top view 93 (3-5/8") 300 (11-7/8") 313 (12-3/8") 13 (1/2") 298 (11-3/4") 233 (9-1/8") 248 (9-3/4") Front view Top view www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 10 YMC-700/YMC-500 YMC-700/YMC-500 MAIN MENU SUB-MENU PARAMETER VALUE [INITIAL VALUE ] Initial Setup Speakers Source Devices Yes / No IR flashers Speaker Auto Speaker Setup Start / Cancel Speaker Configuration Front Large / [Small] Center Large / [Small] / None Surround Bass Out [Both] / Subwoofer / Front Crossover 40Hz / 60Hz / [80Hz] / 100Hz / 120Hz / 160Hz / 200Hz Subwoofer Phase [Normal] / Reverse Speaker Level Test Tone [Off] / On FL (Front L) FR (Front R) C (Center) -20 to +20, [0], step 1 SL (Surround L) SR (Surround R) SWFR (Subwoofer) -20 to +20, [+6], step 1 Reset [Yes] / No Sound Air Surround Xtreme On / Off Adaptive Dynamic Range Control Auto / [Off] Lipsync Auto: -240 to 240 ms, [-240 ms], step 1 ms Manual: 0 to 240 ms, [0 ms], step 1 ms Dynamic Range Min/Auto / Std (standard) / [Max] HDMI Audio Out [Amp] / TV Input Add New Input Cable TV STA–Satellite TV DVD [ 1 ], [ 2 ], [ 3 ], [ 4 ] Blu-ray DVR Game Apple TV [ 1 ], [ 5 ], [ 6 ] CD [ 7 ] Other [ 1 ], [ 2 ], [ 3 ], [ 4 ], [ 7 ] User Input Watch/Listen/Play Remote Code Remote Code Learning Remove Network Network Select [Ethernet] / WLAN (YMC-700) IP Address DHCP Setting [On] / Off IP Address Subnet Mask Default Gateway – – – . – – – . – – – . – – – DNS Server (Primary) DNS Server (Secondary) Wireless LAN MAC Address Filter On / Off MAC Address 1 – MAC Address 10 – – : – – : – – : – – : – – : – – Information MAC Address xx : xx : xx : xx : xx : xx IP Address Subnet Mask Default Gateway x. x. x. x DNS Server (Primary) DNS Server (Secondary) Link Status No Link / 10Base-T / 100Base-TX Method Full Duplex / Half Duplex WLAN Signal Level – – – vTuner ID xxxxxxxxxxxx • SET MENU TABLE [ 1 ] HDMI 1 / HDMI 2 / HDMI 3 [ 2 ] Video 1 + Audio 1 / + Audio 2 / + Audio 3 [ 3 ] Video 2 + Audio 1 / + Audio 2 / Audio 3 [ 4 ] Video 3 + Audio 1 / + Audio 2 / + Audio 3 [ 5 ] Video 1 + Audio 2 / + Audio 3 [ 6 ] Video 2 + Audio 2 / + Audio 3 [ 7 ] Audio 1 / Audio 2 / Audio 3 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 11 YMC-700/YMC-500 YMC-700/YMC-500 MAIN MENU SUB-MENU PARAMETER VALUE [INITIAL VALUE ] Rhapsody Registration Account Status Not Registerd (YMC-700) Registration Input possible Character type Capital: A to Z Small: a to z Figure: 0 to 9 Space Marks: # * + , - . / : < > ? etc. Rhapsody Free Trial Yes / No http://www.rhapsody.com/terms Remove Account Remote Control TV Favorite Preset stations Preset 1 to 8 – – – (channel number) Rename Source Power Control [Enable] / Disable TV Power Control [Enable] / Disable TV Remote Code Select the TV brand. Select the remote control code. TV Remote Code Learning TV POWER TV Power On TV Power Off Option Initial Screen - POWER Button [Top Menu] / Last / Activities Initial Screen - CONTROL Button [Top Menu] / Last / Activities GUI position Horizontal ◀▶ -5 ( ▼ downward / ◀ left) to +5 ( ▲ upward / ▶ right) Vertical ▲▼ HDMI Standby through [Off] / HDMI 1 / HDMI 2 / HDMI 3 Network Standby (YMC-700) [Off] / On Screen Saver Screen Saver Off / [Logos] / Photos Waiting Time 1 min to 10 min, [5 min], step 1 min Preview Factory Reset Yes / [No] Signal Information Video Signal Type – – – ▲ – – – Resolution Audio Decode Status Decode Channel – – – Air Surround Xtreme Update USB Update Network Update (YMC-700) System Information Software Version xx.xx System ID xxxxxxxx www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 12 YMC-700/YMC-500 YMC-700/YMC-500 YMC-700 YMC-500 WIFI P.C.B. (YMC-700) FM TUNER DIGITAL P.C.B. MAIN P.C.B. OPERATION (2) P.C.B. OPERATION (5) P.C.B. OPERATION (1) P.C.B. OPERATION (3) P.C.B. OPERATION (6) P.C.B. OPERATION (4) P.C.B. Top view Front view 4 1 2 3 4 5 6 7 8 9 10 1 3 6 7 10 9 8 2 5 ■ INTERNAL VIEW www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 13 YMC-700/YMC-500 YMC-700/YMC-500 YMC-700 YMC-500 Top cover ass'y Side cover L Side cover R ④ ① ① ⑤ ⑤ ⑤ ④ ③ ② ② CB152 CB153 Front panel unit Hook Hook ■ DISASSEMBLY PROCEDURES (Remove parts in the order as numbered.) Disconnect the power cable from the AC outlet. 1. Removal of Top Cover Ass’y a. Remove 4 screws (①), and remove the side cover L. (Fig. 1) b. Remove 4 screws (②), and remove the side cover R. (Fig. 1) c. Remove 3 screws (③) and 4 screws (④). (Fig. 1) d. Slide the top cover ass’y rearward to lift it. (Fig. 1) e. Remove CB153, and remove the top cover ass’y. (Fig. 1) 2. Removal of Front Panel Unit a. Remove 6 screws (⑤). (Fig. 1) b. Remove CB152. (Fig. 1) c. Release 2 hooks, and remove the front panel unit. (Fig. 1) Fig. 1 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 14 YMC-700/YMC-500 YMC-700/YMC-500 ⑦ ⑧ ⑧ ⑦ ⑨ ⑥ ⑥ ⑦ ⑦ ⑦ ⑧ ⑧ CB382 CB385 CB383 CB363 CB381 CB384 DIGITAL P.C.B 3. Removal of DIGITAL P.C.B. a. Remove 4 screws (⑥). (Fig. 2) b. Remove 5 screw (⑦) and 5 screws (⑧). (Fig. 2) c. Remove CB363 (YMC-700) and CB381–385. (Fig. 2) d. Remove the DIGITAL P.C.B.. (Fig. 2) Fig. 2 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 15 YMC-700/YMC-500 YMC-700/YMC-500 ⑨ ⑩ LAN antenna connector CB100 P.C.B support WIFI P.C.B FM tuner 4. Removal of WIFI P.C.B. (YMC-700) a. Remove the LAN antenna connector by using the U.FL removing tool. (Fig. 3) b. Remove screw (⑨). (Fig. 3) c. Remove the WIFI P.C.B. together with the P.C.B. support. (Fig. 3) CAUTION ! • To remove the LAN antenna connector, use the U.FL removing tool. Hook the tip of this tool on the cover of the connector and pull it straight in the direction of the engaging axis of the connector. Special removing tool AAX72980: U.FL removing tool • When installing the connector, insert it vertically with respect to the WIFI P.C.B. as it is removed from this unit. • The connector can be inserted and removed up to 5 times only. Fig. 3 5. Removal of FM Tuner a. Remove 2 screws (⑩). (Fig. 3) b. Remove CB100. (Fig. 3) c. Remove the FM tuner. (Fig. 3) U.FL removing tool LAN antenna connector www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 16 YMC-700/YMC-500 YMC-700/YMC-500 ⑮ ⑭ ⑪ ⑪ ⑫ ⑭ ⑮ ⑬ CB151 MAIN P.C.B OPERATION (2) P.C.B 6. Removal of MAIN P.C.B. a. Remove 4 screws (⑪), 2 screws (⑫) and 3 screws (⑬). (Fig. 4) b. Remove 6 screws (⑭) and screw (⑮). (Fig. 4) c. Remove CB151. (Fig. 4) d. Remove the MAIN P.C.B.. (Fig. 4) Fig. 4 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 17 YMC-700/YMC-500 YMC-700/YMC-500 Rubber sheet and cloth Chassis Ground lead DIGITAL P.C.B. G3803 CB383 CB385 WQ760200 WQ662700 ST381 CB312 When checking the P.C.B.: • Put the rubber sheet and the cloth over this unit. Then place the DIGITAL P.C.B. upside down on the cloth and check them. (Fig. 5) • Reconnect all cables (connectors) that have been disconnected. Be sure to use the extension cable for servicing for the following section. DIGITAL P.C.B. CB385 – MAIN P.C.B. CB101: WQ662700 (27P, 320mm, P=1.0) DIGITAL P.C.B. CB383 – OPERATION(2) P.C.B. CB154: WQ760200 (17P, 250mm, P=1.0) • When connecting the flexible flat cable, be careful with polarity. • Connect the ground point of each P.C.B. shown below to the chassis with a ground lead or the like. (Fig. 5) DIGITAL P.C.B. G3803 (Ground) DIGITAL P.C.B. ST381 (Ground) DIGITAL P.C.B. CB312 (HDMI) Fig. 5 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 18 YMC-700/YMC-500 YMC-700/YMC-500 TV This unit HDMI cable HDMI IN Fig. 1 ■ UPDATING FIRMWARE Note) The user memories (sound field parameters, system memory, tuner presetting, etc.) are preserved even after the firmware is written. When replacing the following parts, be sure to write the latest firmware. DIGITAL P.C.B. IC344 (Microprocessor FLASH ROM) of DIGITAL P.C.B. IC373 (DSP FLASH ROM) of DIGITAL P.C.B. ● Required Tools • USB storage device • Firmware (YMC700xxxx.bin, YMC500xxxx.bin) • TV with HDMI input terminal (for Confirmation of firmware version and checksum) • HDMI cable (for Confirmation of firmware version and checksum) ● Preparation 1. Download the latest firmware from the specified download source to PC. 2. Copy the latest firmware from the PC to the root folder of the USB storage device. Note) When the firmware is copied to a subfolder of the USB storage device, the update will not proceed. ● Connection Connect this unit and TV as shown below. (Fig. 1) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 19 YMC-700/YMC-500 YMC-700/YMC-500 1: TOTAL VERSION & CHECK SUM The firmware version and checksum value of microprocessor (IC341 DIGITAL P.C.B.) are displayed. 2: DSP VERSION / CHECKSUM The firmware version and checksum value of TI (DSP) FLASH ROM (IC373 DIGITAL P.C.B.) are displayed. 3: FPGA VERSION The firmware version of FPGA (IC331 DIGITAL P.C.B.) is displayed. –> R: ROM VER/SUM 1: TOTAL VERSION & CHECK SUM VERSION : D320 CHECK SUM : 3767 –> R: ROM VER/SUM 2: DSP VERSION & CHECK SUM DSP VERSION : 02.13r4 CHECK SUM : 7295C908 –> R: ROM VER/SUM 3: FPGA VERSION FPGA VER : 27 ● Confirmation of Firmware version and Checksum Before and after writing firmware, check the firmware version and checksum by using the self-diagnostic function menu. Start up the self-diagnostic function and select R. ROM VER/SUM menu. (See “SELF-DIAGNOSTIC FUNCTION”) Using the sub-menu, have the firmware version and checksum displayed, and note down them. R: ROM VER/SUM Example www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 20 YMC-700/YMC-500 YMC-700/YMC-500 TV screen Writing is started. USB UPDATE FILE READ xx% USB UPDATE BLOCK x xx% UPDATE FINISH AC TURN OFF Writing is being executed. Writing is completed. USB terminal Rear view "〈" (UP) key Top view "CONTROL" key 2. While pressing the “CONTROL” and “〈” (UP) keys of this unit, connect the power cable to the AC outlet. (Fig. 3) Release the “CONTROL” and “〈” (UP) keys when the POWER indicator (left side) lights. (Fig. 5) Writing of the firmware is started. While writing the firmware, the screen is displayed as shown below. (Fig. 4) Fig. 3 Fig. 4 1. Insert the USB storage device, in which the latest firmware is stored, to the USB terminal located on the rear panel of this unit. (Fig. 2) Fig. 2 ● Operation Procedures www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 21 YMC-700/YMC-500 YMC-700/YMC-500 Supplementary information When writing of the firmware is started, the power indicator (left side) lights. If an error occurs while writing the firmware, the power indicator (right side) lights and the power indicator (left side) goes off. POWER indicator (left side) This unit POWER indicator (right side) 3. When writing of the firmware is completed, the power of this unit turns off automatically. * When an error message is displayed before writing is completed, perform the operation procedures from step 1 to 3 again. 4. Start up the self-diagnostic function and select R. ROM VER/SUM menu. Using the sub-menu, have the firmware version and checksum displayed, and then check that they are the same as written ones. * When the displayed firmware version and checksum are different from written ones, perform the Operation Procedures again. 5. Press the “STANDBY/ON” key to turn off the power. Error messages Contents NO DEVICE The USB storage device is not connected. NO FILE The firmware is not found in the USB storage device. INVALID FILE The firmware is not applicable to YMC-700/YMC-500. BLOCK x ERROR The firmware writing error on Block x. Fig. 5 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 22 YMC-700/YMC-500 YMC-700/YMC-500 ■ SELF-DIAGNOSTIC FUNCTION This unit has self-diagnostic functions that are intended for inspection, measurement and location of faulty point. There are 20 main menu items, each of which has sub-menu items. Listed in the table below are menu items and sub-menu items. Note that not all menu items listed will apply to the models covered in this service manual. MAIN MENU SUB MENU Code Category No. Function A: AUDIO CHECK 1: OPTICAL INPUT PLAYBACK (normal) 2: OPTICAL INPUT PLAYBACK (all channels) 3: COAXIAL INPUT PLAYBACK (normal) 4: COAXIAL INPUT PLAYBACK (all channels) 5: ANALOG AUDIO PLAYBACK (normal) 6: ANALOG AUDIO PLAYBACK (all channels) 7: MUTE ALL 8: MUTE SUBWOOFER B: SPEAKERS SET 1: FRONT : SML 2: CENTER : NONE 3: LFE/B : FRONT 4: TONE : MAX. 5: TONE : MIN. C: MIC CHECK 1: MIC CHECK D: TEST TONE 1: TEST ALL 2: TEST FRONT L 3: TEST CENTER 4: TEST FRONT R 5: TEST SURROUND R 6: TEST SURROUND L 7: TEST LFE (SUBWOOFER) E: USB 1: USB File 1 2: USB File 2 3: USB Memory ACCESS TEST F: ETHERNET 1: INTERNAL LOOPBACK 10BaseT 2: INTERNAL LOOPBACK 100BaseTx 3: EXTERNAL LOOPBACK 10BaseT 4: EXTERNAL LOOPBACK 100BaseTx 5: GET IP ADDRESS FROM DHCP SERVER 6: TRANSMIT DATA G: WiFi 1: GET IP ADDRESS FROM DHCP SERVER 2: WiFi MODULE FIRMWARE DOWNLOAD 3: SHOW DEVICE SERIAL NO. 4: GET WiFi FIRMWARE VERSION 5: TEST MODE : SI 1 6: TEST MODE : SI 2 7: TEST MODE : SI 3 8: TEST MODE : SI 4 9: TEST MODE : SI 5 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 23 YMC-700/YMC-500 YMC-700/YMC-500 MAIN MENU SUB MENU Code Category No. Function H: VIDEO CONVERSION 1: VIDEO INFO. 2: DEINTERLACE ON/OFF 3: CONVERSION CVBS 4: CONVERSION COMPONENT 1 (CP) 5: CONVERSION COMPONENT 2 (CP) 6: CONVERSION iPod 7: CONVERSION COMPONENT 1 (SDP) 8: CONVERSION COMPONENT 2 (SDP) J: HDMI 1: HDMI IN1 (HDMI AUDIO = AMP) 2: HDMI IN2 (HDMI AUDIO = AMP) 3: HDMI IN3 (HDMI AUDIO = AMP) 4: HDMI IN1 (HDMI AUDIO = TV) 5: HDMI IN2 (HDMI AUDIO = TV) 6: HDMI IN3 (HDMI AUDIO = TV) K: DOCK 1: DOCK CONNECTION TEST 2: BLUETOOTH VERSION 3: CLEAR BLUETOOTH PAIRING INFO. 4: WATCH iPod L: IR Blaster 1: SEND KEY 2: LEARNING 3: VERSION 4: LOOP BACK 5: LOOP BACK LEARNED M: AD DATA 1: KEY1 : xxx, KEY2 : xxx 2: PRV1 : xxx 3: DC_PRT : xxx 4: DOCK_ID : xxx 5: IP_AP : xxx 6: IP_DET : xxx 7: DEST1 : xxx, DEST2 : xxx N: PROTECTION 1: PRV1 : xxx 2: DC_PRT : xxx P: PROTECTION HISTORY 1: DISPLAY PROTECTION HISTORY Q: FACTORY PRESET 1: PRESET INHI 2: PRESET RSRV R: ROM VER/SUM 1: TOTAL VERSION and CHECK SUM 2: DSP VERSION and CHECK SUM 3: FPGA VERSION S: DEVICE ACCESS CHECK 1 1: EXTERNAL BUS DEVICES access check 2: EEPROM DEVICES access check 3: WiFi MODULE access check 4 VIDEO (I2C0) DEVICES access check 5: PWM (I2C1) DEVICES access check www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 24 YMC-700/YMC-500 YMC-700/YMC-500 MAIN MENU SUB MENU Code Category No. Function S: DEVICE ACCESS CHECK 1 6: DSP and DIR (SPI0) DEVICES access check 7: FPGA (SPI2) DEVICES access check 8: IR BLASTER (UART0) DEVICES access check T: DEVICE ACCESS CHECK 2 1: EXTERNAL BUS DEVICES (devices on DIGITAL P.C.B.) U: SERIAL No. 1: Display Serial No 2: Write Serial No by barcode reader V: TUNER 1: TUNER RANGE (LOWER) 2: TUNER RANGE (UPPER) 3: TUNER RANGE (MIDDLE) 4: AUTO TUNING www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 25 YMC-700/YMC-500 YMC-700/YMC-500 TV This unit HDMI cable HDMI IN "STANDBY/ON" key While pressing these keys, turn on the power. "〉" (DOWN) key "CONTROL" key Fig. 1 ● Required Tools • TV with HDMI input terminal • HDMI cable ● Connection Connect this unit and TV as shown below. (Fig. 1) ● Starting Self-Diagnostic Function While pressing those 2 keys of this unit as shown in the figure below, press the “STANDBY/ON” key to turn on the power and keep pressing those 2 keys for longer than 2 seconds. The self-diagnostic function mode is activated. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 26 YMC-700/YMC-500 YMC-700/YMC-500 Opening message –> A: AUDIO CHECK P: PROTECTION HISTORY 1: DISPLAY PROTECTION HISTORY Last : PRI xxx 2nd : PRD xxx 3rd : PRV xxx 4th : THM xxx VOLUME: 25 AUDIO: – – VIDEO: – – Main menu A: AUDIO CHECK When there is no history of protection function When there is a history of protection function After a few seconds Press "ENTER" key –> P: PROTECTION HISTORY 1: DISPLAY PROTECTION HISTORY No Protection has be detected VOLUME: 25 AUDIO: – – VIDEO: – – ● Canceling Self-Diagnostic Function 1. Before canceling self-diagnostic function, execute setting of main menu Q.FACTORY PRESET (Memory initialization inhibited or Memory initialized). * In order to keep the user memory stored, be sure to select PRESET INHIBITED (Memory initialization inhibited). 2. Press the “STANDBY/ON” key of this unit to turn off the power. ● Display provided when Self-Diagnostic Function started The TV screen displays the “neo HD” logo, followed by the protection function information after a few seconds. Press “ENTER” key of this unit. The main menu is displayed. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 27 YMC-700/YMC-500 YMC-700/YMC-500 PRI xxx PRD xxx When there is a history of protection function due to excess current When there is a history of protection function due to abnormal DC output Cause: An excessive current flowed through the power amplifier. Supplementary information: As current of the power amplifier is detected, the abnormal channel can be identified by checking the current detect transistor. Turning on the power without correcting the abnormality will cause the protection function to work immediately and the power supply will instantly be shut off. Cause: DC output of the power amplifier is abnormal. Supplementary information: The protection function worked due to a DC voltage appearing at the speaker terminal. A cause could be a defect in the amplifier. Turning on the power without correcting the abnormality will cause the protection function to work in 3 seconds and the power supply will be shut off. AD value is displayed, when the protection function is working AD value is displayed, when the protection function is working Note) • Applying the power to this unit without correcting the abnormality can be dangerous and cause additional circuit damage. To avoid this, if “PRI” and “PRD” protection function has been activated 3 times continuously, the power will not turn on even when the “STANDBY/ON” key is pressed. In order to turn on the power again, disconnect the power cable of this unit from the AC outlet once and then reconnect it again. • The output transistors in each amplifier channel should be checked for damage before applying power to this unit. • Amplifier current should be monitored by measuring DC voltage across the emitter resistors for each channel. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 28 YMC-700/YMC-500 YMC-700/YMC-500 THM xxx PRV xxx When there is a history of protection function due to excessive D-AMP temperature Cause: The temperature of the D-AMP is excessive. Supplementary information: The protection function worked due to the temperature exceeding limit. Causes could be poor ventilation or a defect related to the thermal sensor. Turning on the power without correcting the abnormality will cause the protection function to work in 1 second and the power supply will be shut off. For detection of each protection function, refer to main menu described later. AD value is displayed, when the protection function is working ● History of protection function When the protection function has worked, its history is stored in backup memory. Even if no abnormality is noted while servicing the unit, an abnormality which has occurred previously can be defined as long as the backup data has been stored. For details of the history of protection function, refer to main menu P: PROTECTION HISTORY. The history of the protection function is cleared when self-diagnostic function is cancelled by selecting main menu N: PRESET RESERVED (Memory initialized) or when the backup data is erased. When there is a history of protection function due to abnormal voltage in the power supply section Cause: The voltage in the power supply section is abnormal. Supplementary information: The protection function worked due to a defect or overload in the power supply. Turning on the power without correcting the abnormality will cause the protection function to work in 1 second and the power supply will be shut off. AD value is displayed, when the protection function is working www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 29 YMC-700/YMC-500 YMC-700/YMC-500 –> –> Main menu Sub-menu Messages Volume Audio input Video input A: AUDIO CHECK 2: OPTICAL INPUT PLAYBACK (all) –> –> A: AUDIO CHECK 1: OPTICAL INPUT PLAYBACK (normal) A: AUDIO CHECK 1: OPTICAL INPUT PLAYBACK (normal) NOW EXECUTING VOLUME: 25 AUDIO: OPTICAL VIDEO: – – –> B: SPEAKER SET –> A: AUDIO CHECK GUI specification Press "〈 (UP)" key Press "〉 (DOWN)" key Press "〈 (UP)" key Press "〉 (DOWN)" key Press "〈 (UP)" key Press "〉 (DOWN)" key Press "〈 (UP)" key Press "〉 (DOWN)" key Press "ENTER" key Press "BACK" key Press "ENTER" key Press "BACK" key "–>" is a cursor which indicates currently selected menu layer. –> [Main menu] [Main menu] Next main menu Next sub-menu [Sub-menu] [Sub-menu] [Execution of selected item] "〈" (UP) key Enter selected menu Return to upper menu Select Main menu and Sub-menu "〉" (DOWN) key ● Operation procedure of Main menu and Sub-menu There are 20 main menu items, each of them having sub-menu items. Keys of this unit Keys of this unit Function 〈 (UP) and 〉 (DOWN) Select Main menu and Sub-menu 〈 (LEFT) and 〉 (RIGHT) Not used ENTER Enter selected menu CONTROL Not used BACK Return to upper menu www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 30 YMC-700/YMC-500 YMC-700/YMC-500 ● Functions in Self-Diagnostic Function mode In addition to the self-diagnostic function menu items, functions as listed below are available. • Power ON/OFF • Master volume * Functions related to the tuner and the setup menu are not available. ● Initial setting used to start Self-Diagnostic Function The following initial setting is used when starting self-diagnostic function. When self-diagnostic function is canceled, this setting is restored to that before starting self-diagnostic function. • Master volume: 25 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 31 YMC-700/YMC-500 YMC-700/YMC-500 –> A: AUDIO CHECK 1: OPTICAL INPUT PLAYBACK (normal) NOW EXECUTING VOLUME: 25 AUDIO: OPTICAL VIDEO: – – ● Details of Self-Diagnostic Function menu A: AUDIO CHECK Using the sub-menu, the audio input signal is selected and output. 1: OPTICAL INPUT PLAYBACK (Normal) Audio input select: OPTICAL 5: ANALOG AUDIO PLAYBACK (normal) Audio input select: ANALOG 3: COAXIAL INPUT PLAYBACK (Normal) Audio input select: COAXIAL 7: MUTE ALL All output channels are muted. Audio input select: ANALOG 8: MUTE SUBWOOFER Only subwoofer output is muted. Audio input select: ANALOG 2: OPTICAL INPUT PLAYBACK (all channels) Audio input select: OPTICAL When the stereo signal is input from OPTICAL INPUT, the input signal is assigned as shown below. FRONT L : FRONT L, SURROUND L, CENTER FRONT R : FRONT R, SURROUND R, SUBWOOFER 6: ANALOG AUDIO PLAYBACK (all channels) Audio input select: ANALOG The audio signal input from ANALOG INPUT is assigned as shown below. FRONT L : FRONT L, SURROUND L, CENTER FRONT R : FRONT R, SURROUND R, SUBWOOFER 4: COAXIAL INPUT PLAYBACK (all channels) Audio input select: COAXIAL When the stereo signal is input from COAXIAL INPUT, the input signal is assigned as shown below. FRONT L : FRONT L, SURROUND L, CENTER FRONT R : FRONT R, SURROUND R, SUBWOOFER Example www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 32 YMC-700/YMC-500 YMC-700/YMC-500 –> B: SPEAKER SET 1: FRNT: SML NOW EXECUTING VOLUME: 25 AUDIO: ANALOG VIDEO: – – B: SPEAKER SET Using the sub-menu, the audio input signal is selected and output. 1: FRONT : SML 0dB The signal, 90 Hz or lower, is mixed into the channel specified by LFE/BASS. Audio input select: ANALOG 2: CENTER : NONE The CENTER signal is distributed to FRONT L/R. Audio input select: OPTICAL 5: TONE : MIN The audio signal is output with the tone control “BASS -6 dB, TREBLE -6 dB”. Audio input select: ANALOG 3: LFE / BASS : FRONT The LFE/BASS signal is distributed to FRONT L/R. Audio input select: OPTICAL The analog switch settings for each sub-menu are as shown in the table below. 4: TONE : MAX The audio signal is output with the tone control “BASS +6 dB, TREBLE +6 dB”. Audio input select: ANALOG LARGE : This mode is used for a speaker with high bass reproduction performance (a large unit). Full bandwidth signals are output. SMALL : This mode is used for a speaker with low bass reproduction performance (a small unit). The signals of 90 Hz or less are mixed into the channel specified by LFE/BASS. NONE : This mode is used for no center speaker. The center content is reduced by -3 dB and distributed to FRONT L/R. SWFR : LFE of 5.1 ch signal or LFE/BASS lower than 90 Hz is output through SUBWOOFER OUT. FRONT : LFE of 5.1 ch signal or LFE/BASS lower than 90 Hz is distributed to FRONT L/R. FRONT CENTER SURROUND SUBWOOFER 1 FRONT : SML 0dB SMALL LARGE LARGE SWFR 2 CENTER : NONE LARGE NONE LARGE SWFR 3 LFE / BASS : FRONT LARGE SMALL SMALL FRONT 4 TONE : MAX LARGE LARGE LARGE SWFR 5 TONE : MIN LARGE LARGE LARGE SWFR Example www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 33 YMC-700/YMC-500 YMC-700/YMC-500 –> C: MIC CHECK 1: MIC CHECK NOW EXECUTING VOLUME: 25 AUDIO: MIC VIDEO: – – –> D: TEST TONE 1: TEST ALL NOW EXECUTING VOLUME: 25 AUDIO: – – VIDEO: – – C: MIC CHECK This menu is used to check MIC. D: TEST TONE The built-in noise generator of DSP outputs the test noise through the channels specified by using the sub-menu. The noise frequency for LFE is 30 to 80 Hz. Other than that, the noise frequency is 500 Hz to 2 kHz. 1: MIC CHECK The signal input through the microphone is output via A/D – D/A. Audio input select: MIC 1: TEST ALL The test noise is output from all channels. 5: TEST SURROUND R The test noise is output from SURROUND R channel. 2: TEST FRONT L The test noise is output from FRONT L channel. 6: TEST SURROUND L The test noise is output from SURROUND L channel. 3: TEST CENTER The test noise is output from CENTER channel. 7: TEST LFE (SUBWOOFER) The test noise is output from LFE channel. 4: TEST FRONT R The test noise is output from FRONT R channel. Example Example www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 34 YMC-700/YMC-500 YMC-700/YMC-500 –> E: USB 1: USB FILE 1 FILE NAME: – – – Result : NG Can not open fi le VOLUME: 25 AUDIO: USB VIDEO: – – –> E: USB 1: USB FILE 1 FILE NAME: xxxxxxxxx Result : OK VOLUME: 25 AUDIO: USB VIDEO: – – E: USB This menu is used to check USB interface. Preparation of USB storage device a. Copy 2 or more music files from PC to the root folder of a USB storage device. b. Insert the USB storage device to the USB terminal of this unit. 1: USB FILE 1 The 1st music file stored in the USB storage device connected to the USB terminal is reproduced. Audio input select: USB 3: USB MEMORY ACCESS TEST This menu is used to check Read/Write/ Compare of USB storage device. 2: USB FILE 2 The 2nd music file stored in the USB storage device connected to the USB terminal is reproduced. Audio input select: USB When the USB storage device is not connected or no music file is stored in the USB storage device, the screen appears as shown below Example Example Example Result : OK Example Result : OK Example Result : OK www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 35 YMC-700/YMC-500 YMC-700/YMC-500 –> F: ETHERNET 1: INTERNAL LOOPBACK 10BaseT Result: OK VOLUME: 25 AUDIO: – – VIDEO: – – –> F: ETHERNET 5: GET IP ADDRESS FROM DHCP SERVER IP address: xxx.xxx.xxx.xxx Subnetmask: yyy.yyy.yyy.yyy VOLUME: 25 AUDIO: – – VIDEO: – – 1 2 3 4 5 6 7 8 F: ETHERNET (YMC-700 model) This menu is used to check the NETWORK communication. 1: INTERNAL LOOPBACK 10 BaseT The internal loopback test (10Mbps) of the PHY (IC362, DIGITAL P.C.B.) is executed. 4: EXTERNAL LOOPBACK 100 BaseTx Loopback test (100Mbps) 6: TRANSMIT DATA Not applied to these models. 2: INTERNAL LOOPBACK 100 BaseTx The internal loopback test (100Mbps) of the PHY (IC362, DIGITAL P.C.B.) is executed. 5: GET IP ADDRESS FROM DHCP SERVER Connect the NETWORK connector of this unit to the LAN connector of network router with a CAT-5 or higher STP cable. When the IP address is obtained from DHCP server, IP ADDRESS and SUBNET MASK are displayed. 3: EXTERNAL LOOPBACK 10 BaseT This menu is used to check the NETWORK connector. With the power to this unit turned off, short between pins No. 1 (Tx+) and No. 3 (Rx+) and between pins No. 2 (Tx-) and No. 6 (Rx-) of the NETWORK connector. (Be sure to turn off the power to this unit when shorting these pins.) Start up the self-diagnostic function and select this menu. Loopback test (10Mbps) Note) Be sure to return the shorted pins to their original condition after executing this test. Example Example Example Result: OK Example Result: OK Example Result: OK Example Result: OK www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 36 YMC-700/YMC-500 YMC-700/YMC-500 –> G: WiFi 1: GET IP ADDRESS FROM DHCP SERVER IP address: xxx.xxx.xxx.xxx Subnetmask: yyy.yyy.yyy.yyy VOLUME: 25 AUDIO: – – VIDEO: – – –> H: VIDEO CONVERSION 1: VIDEO INFO NTSC, 480i@60 VOLUME: 25 AUDIO: – – VIDEO: – – G: WiFi (YMC-700 model) This menu is used to check the WiFi connection. H: VIDEO CONVERSION This menu is used to check the video input signal. 1: GET IP ADDRESS FROM DHCP SERVER IP ADDRESS and SUBNET MASK obtained from DHCP server are displayed. 1: VIDEO INFORMATION The information of video signal input from VIDEO IN 1 (or VIDEO IN 2 or VIDEO IN 3) terminal is displayed. 2: DEINTERLACE ON/OFF Using the “ 〈 (UP)” and “ 〉 (DOWN)” keys, it is possible to turn the DEINTERLACE on/off. 2: WiFi MODULE FIRMWARE DOWNLOAD The firmware is downloaded from microprocessor to WiFi module. 4: GET WiFi FIRMWARE VERSION The firmware version of WiFi module is displayed. 3: SHOW DEVICE SERIAL NO. The serial number ID of WiFi module is displayed. Example Example Example fi rmware version : x.x.xxxxxx Example Deinterlace : ON Example ID : xxxxxxxxxxxx Example Result: Boot OK www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 37 YMC-700/YMC-500 YMC-700/YMC-500 CONVERSION CVBS HDMI IN VIDEO IN 1/2 (COMPONENT 1/2) HDMI OUT VIDEO IN 3 (CVBS) DOCK IN DIGITAL HDMI transmitter ADV7510 IC321 DIGITAL FPGA EP2C8Q208 IC331 DIGITAL HDMI receiver Video decoder ADV7840 IC311 CP Component processor SDP Standard definition processor CONVERSION COMPONENT 1 / 2 (CP) HDMI IN VIDEO IN 1/2 (COMPONENT 1/2) HDMI OUT VIDEO IN 3 (CVBS) DOCK IN DIGITAL HDMI transmitter ADV7510 IC321 DIGITAL FPGA EP2C8Q208 IC331 DIGITAL HDMI receiver Video decoder ADV7840 IC311 CP Component processor SDP Standard definition processor 480p, 576p, 720p, 1080i, 1080p 3: CONVERSION CVBS The video signal input from VIDEO IN 3 (CVBS) is output after undergoing video up-conversion. 4: CONVERSION COMPONENT 1 (CP) The video signal input from VIDEO IN 1 (COMPONENT 1) is output after undergoing video up-conversion. The video signal is output via CP (Component Processor) in the decoder (IC311 DIGITAL P.C.B.). Output video signals: 480p, 576p, 720p, 1080i, 1080p 5: CONVERSION COMPONENT 2 (CP) The video signal input from VIDEO IN 2 (COMPONENT 2) is output after undergoing video up-conversion. The video signal is output via CP (Component Processor) in the decoder (IC311 DIGITAL P.C.B.). Output video signals: 480p, 576p, 720p, 1080i, 1080p www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 38 YMC-700/YMC-500 YMC-700/YMC-500 CONVERSION iPod HDMI IN VIDEO IN 1/2 (COMPONENT 1/2) HDMI OUT VIDEO IN 3 (CVBS) DOCK IN DIGITAL HDMI transmitter ADV7510 IC321 DIGITAL FPGA EP2C8Q208 IC331 DIGITAL HDMI receiver Video decoder ADV7840 IC311 CP Component processor SDP Standard definition processor CONVERSION COMPONENT 1 / 2 (SDP) HDMI OUT DIGITAL HDMI transmitter ADV7510 IC321 DIGITAL FPGA EP2C8Q208 IC331 DIGITAL HDMI receiver Video decoder ADV7840 IC311 CP Component processor SDP Standard definition processor 480i, 576i HDMI IN VIDEO IN 1/2 (COMPONENT 1/2) VIDEO IN 3 (CVBS) DOCK IN 6: CONVERSION iPod The video signal input from DOCK (iPod) is output after undergoing video up-conversion. 7: CONVERSION COMPONENT 1 (SDP) The video signal input from the VIDEO IN 1 (COMPONENT 1) is output after undergoing video up-conversion. The video signal is output via SDP (Standard Definition Processor) in the decoder (IC311 DIGITAL P.C.B.). Output video signals: 480i, 576i 8: CONVERSION COMPONENT 2 (SDP) The video signal input from VIDEO IN 2 (COMPONENT 2) is output after undergoing video up-conversion. The video signal is output via SDP (Standard Definition Processor) in the decoder (IC311 DIGITAL P.C.B.). Output video signals: 480i, 576i www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 39 YMC-700/YMC-500 YMC-700/YMC-500 –> J: HDMI 1: HDMI IN1 (HDMI AUDIO = AMP) J: HDMI Using the sub-menu, the selected input signal is output to HDMI OUT. 1: HDMI IN1 (HDMI AUDIO = AMP) The signal input from HDMI IN1 is output. Audio output: AMP (This unit) 4: HDMI IN1 (HDMI AUDIO = TV) The signal input from HDMI IN1 is output. Audio output: TV 2: HDMI IN2 (HDMI AUDIO = AMP) The signal input from HDMI IN2 is output. Audio output: AMP (This unit) 5: HDMI IN2 (HDMI AUDIO = TV) The signal input from HDMI IN2 is output. Audio output: TV 3: HDMI IN3 (HDMI AUDIO = AMP) The signal input from HDMI IN3 is output. Audio output: AMP (This unit) 6: HDMI IN3 (HDMI AUDIO = TV) The signal input from HDMI IN3 is output. Audio output: TV Example www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 40 YMC-700/YMC-500 YMC-700/YMC-500 –> K: DOCK 1: DOCK CONNECTION TEST Total Check : NG [ UART Loopback : Wrong ] [ iPAP and iPDET : No and No ] [ Dock Type : Error ] VOLUME: 25 AUDIO: – – VIDEO: – – 1 2 19 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 20 21 10 k-ohms 1/4 W K: DOCK This menu is used to check the DOCK connector. 3: CLEAR BLUETOOTH PAIRING INFORMATION This menu is used to reserve/inhibit initialization of pairing data in the Bluetooth DOCK (YBA-10) connected to the DOCK connector. Using the “ 〈 (UP)” or “ 〉 (DOWN)” key, it is possible to select the Clear: Inhibit or Reserved. Clear: Inhibit Initialization of pairing data is not executed. Select this sub-menu to protect the pairing data. Clear: Reserved Initialization of pairing data is reserved. Select this sub-menu to reset the pairing data. 4: WATCH iPod The 1st video content stored in the iPod connected to the DOCK connector is reproduced. 1: DOCK CONNECTION TEST This menu is used to check the DOCK connector without the iPod itself. With the power to this unit turned off, short between pins No. 14 (TX) and No. 18 (RX), between pins No. 1 (PWR) and No. 17 (ACCPOW), between pins No. 4 (iPDET) and No. 8 (DGND). Also, connect a 10 k-ohms, 1/4 W resistor between pins NO. 21 (DOCK_ ID) and No. 8 (DGND). (Make sure that the power is turned off when shorting pins.) Start up the self-diagnostic function and select this menu. The check result is displayed according to the following display specifications. Note) Be sure to return the shorted pins to their original condition after executing this test. 2: BLUETOOTH VERSION The firmware version of Bluetooth DOCK (YBA-10) connected to the DOCK connector is displayed. Check Item Short Pins Display Result UART Loopback test Pins No.14 (TX) – No.18 (RX) Correct Y Wrong iPAP (iPod accessory power) detection Pins No.1 (PWR) – No.17 (ACCPOW) Yes (High) Y No (Low) iPDET (iPod installation to DOCK) detection Pins No.4 (iPDET) – No.8 (DGND) No (High: not installed) Yes (Low: installed) Y Dock Type (DOCK ID) detection Pins No.21 (DOCK_ID) – No.8 (DGND) * 10 k-ohms, 1/4 W pull down Bluetooth Normal (iPod DOCK) Y Error (No connected) * Pull down resistor: Bluetooth 560 ohms, 1/4W All “Y” = Total Check “OK” Example Example BTYR x.xx www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 41 YMC-700/YMC-500 YMC-700/YMC-500 –> L: IR BLASTER 1: SEND KEY Result : 00 PASS VOLUME: 25 AUDIO: – – VIDEO: – – 3.5mm mini plug cable L: IR BLASTER This menu is used to check the IR blaster (IC383 of the DIGITAL P.C.B.) and remote control connection. 1: SEND KEY The remote code, which is stored when executing “2. LEARNING” described below, is output to REMOTE CONTROL OUT. Result No. Message 00 PASS OK 01 Invalid device code NG 02 Invalid device type 03 Invalid key code 04 Bad FDRA 06 Error or time out 07 Learning Error or time out 08 Format Error 09 Already existed 10 Low voltage 99 Blaster do not respond 5: LOOP BACK LEARNED This menu is used to execute the loop back test of REMOTE CONTROL connector. The remote code, which is stored when executing “2. LEARNING” described above, is output to REMOTE CONTROL OUT. 2: LEARNING The remote code, which is input from remote control sensor on front panel of this unit, is stored. Select this menu, then using the remote control transmit the remote code to be stored toward the remote control sensor on front panel of this unit. 3: VERSION The firmware version of IR blaster (IC383 DIGITAL P.C.B.) is displayed. Note) Be sure to remove the a mini-plug (3.5 mm) cable after executing this test. Example 4: LOOP BACK This menu is used to execute the loop back test of REMOTE CONTROL connector. With the power to this unit turned off, connect OUT1 (or OUT2 or OUT3) to IN of remote control connectors with a mini-plug (3.5 mm) cable. Start up the self-diagnostic function and select this menu. Loop back test is executed and check result is displayed as shown below. * Remote code for loop back test : “7A851DE2” Example Total : PASS [ Blaster : 00 ] PASS [ Receiving : 7A851CE3 ] Total : NG [ Receiving : NOT xxxxxxxx ] Total : NG [ Receiving : NOT xxxxxxxx ] Example 31353135 Example Total : PASS [ Blaster : 00 ] PASS [ Receiving : 7A851DE2 ] Example Result : 00 PASS www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 42 YMC-700/YMC-500 YMC-700/YMC-500 –> M: A/D DATA 1: KEY1 : 255 KEY2: 255 HL VOLUME: 25 AUDIO: – – VIDEO: – – M: A/D DATA This menu is used to display the A/D conversion value of the microprocessor which detects panel keys of this unit and protection functions by using the sub-menu. When KEY1/KEY2 menu is selected, keys become nonoperable due to detection of the values of all keys. However, it is possible to return to preceding mode, in which keys become operable again, by turning the “VOLUME” knob of this unit. 1: KEY1: : KEY2: (Panel key of this unit) When the A/D conversion value of the panel key becomes out of the specified range (standard value ±4), normal operation will not be available. In this case, check the constant of voltage dividing resistor, solder condition, etc. Refer to table. (Reference voltage: 3.3V=255) 2: PRV1: Power supply voltage protection detection. Voltage detects: +12A, +6V, +5V, +5A, -5A, +3.3V, +2.5V Port detect: Pin No. 5 of IC381 Normal value: 133 to 190 (Reference voltage: 3.3 V=255) 4: DOCK_ID: DOCK type detection (Reference voltage: 3.3V=255) Port detect: Pin No. 15 of IC382 3: DC_PRT: (PRD) Power amplifier DC (DC voltage) output is detected. Voltage detects: SP_FL±, SP_FR±, SP_C±, SP_SL±, SP_SR± Port detect: Pin No. 1 of IC382 Normal value: 139 to 216 (Reference voltage: 3.3 V=255) Displayed KEY1 (7 pin of IC381) 0 – 4 〈 (LEFT) 40 – 52 〈 (UP) 98 – 110 〉 (RIGHT) 148 – 160 〉 (DOWN) 201 – 213 ENTER 255 Key off Displayed KEY2 (6 pin of IC381) 0 – 4 CONTROL 121 – 133 BACK 255 Key off DOCK detection for AD port Pull-up resistance 10 k-ohms DOCK type (15 pin of C382) A/D value (3.3V=255) Bluetooth 5 – 25 iPod 120 – 140 No connected 250 – 255 Example Volume knob detection Port detect: VOL_RA: Pin No. 64 of IC351 VOL_RB: Pin No. 67 of IC351 H: High, L: Low Example 4: DOCK_ID: 252 Example 3: DC_PRT : 175 Example 2: PRV1 : 148 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 43 YMC-700/YMC-500 YMC-700/YMC-500 –> N: PROTECTION 1: PRV1 : 133/190 VOLUME: 25 AUDIO: – – VIDEO: – – 5: IP_AP: iPAP (iPod accessory power) detection. (Reference voltage: 3.3V=255) Port detect: Pin No. 14 of IC382 iPod installed: 250 to 255 iPod not installed: 135 to 165 6: IP_DET: iPDET (iPod installation to DOCK) detection. (Reference voltage: 3.3V=255) Port detect: Pin No. 12 of IC382 iPod installed: 0 to 5 iPod not installed: 250 to 255 7: DEST1: : DEST2: DEST1: Destination detection. (Reference voltage: 3.3V=255) Port detect: Pin No. 5 of IC382 DEST2: Model detection. (Reference voltage: 3.3V=255) Port detect: Pin No. 2 of IC382 Destination U R3863 DIGITAL P.C.B. 8.2 k R3864 DIGITAL P.C.B. 1 k V 0.27 – 0.44 Detection value 27 ±4 Model name YMC-700 YMC-500 R3865 DIGITAL P.C.B. 8.2 k 5.6 k R3866 DIGITAL P.C.B. 1 k 5.6 k V 0.27 – 0.44 1.57 – 1.72 Detection value 21 – 34 121 – 133 DEST1 Destination detection for A/D port DEST2 Model detection for A/D port N: PROTECTION This menu is used to display the protection function setting values. 1: PRV1: Setting values of power supply voltage protection are displayed. 2: DC_PRT: (PRD) Setting values of power amplifier DC (DC voltage) output protection are displayed. Example Example 1: PRV1 : 133/190 Example 2: DC_PRT : 139/216 Example 7: DEST1 : 27 DEST2: 27 Example 5: IP_AP : 144 Example 6: IP_DET : 252 Upper Lower Upper Lower www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 44 YMC-700/YMC-500 YMC-700/YMC-500 –> P: PROTECTION HISTORY 1: DISPLAY PROTECTION HISTORY Last : PRI xxx 2nd : PRV xxx 3rd : PRD xxx 4th : THM xxx VOLUME: 25 AUDIO: – – VIDEO: – – –> Q: FACTORY PRESET 1: PRESET INHI VOLUME: 25 AUDIO: – – VIDEO: – – P: PROTECTION HISTORY The history of protection function is displayed up to 4. A/D value is displayed when the protection function works. (Reference voltage: 3.3 V=255) Q: FACTORY PRESET This menu is used to reserve/inhibit initialization of the back-up IC. 1: PRESET INHI PRESET INHIBIT (Initialization inhibited) Back-up IC initialization is not executed. Select this sub-menu to protect the values set by the user. 2: PRESET RSRV PRESET RESERVED (Initialization reserved) Initialization of the back-up IC is reserved. (Actually, initialization is executed the next time that the power is turned on.) Select this sub-menu to reset to the original factory settings or to reset the back-up IC. Any protection history will be cleared. CAUTION: Before setting to the PRESET RESERVED, write down the existing preset memory content of the tuner in a table. (This is because setting to the PRESET RESERVED will cause the user memory content of the tuner to be erased.) Example Example www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 45 YMC-700/YMC-500 YMC-700/YMC-500 –> R: ROM VER/SUM 1: TOTAL VERSION & CHECK SUM VERSION : D320 CHECK SUM : 3767 VOLUME: 25 AUDIO: – – VIDEO: – – R: ROM VER/SUM This menu is used to display the firmware version and checksum. The checksum is obtained by adding the data at every 8 bits for each program area and expressing the result as a 4figure hexadecimal data. 1: TOTAL VERSION / CHECKSUM The firmware version and checksum value of microprocessor (IC341 DIGITAL P.C.B.) are displayed. 2: DSP VERSION / CHECKSUM The firmware version and checksum value of TI (DSP) FLASH ROM (IC373 DIGITAL P.C.B.) are displayed. 3: FPGA VERSION The firmware version of FPGA (IC331 DIGITAL P.C.B.) is displayed. Example Example FPGA VER : 27 Example DSP VERSION : 02.13r4 CHECK SUM : 7295C908 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 46 YMC-700/YMC-500 YMC-700/YMC-500 –> S: DEVICE ACCESS CHECK 1 1: EXTERNAL BUS DEVICES USB : OK ETHERNET : OK NPGA : OK SDIO I/F : OK VOLUME: 25 AUDIO: – – VIDEO: – – S: DEVICE ACCESS CHECK 1 This menu is used to check communication and bus line connection between devices on the DIGITAL P.C.B.. 1: EXTERNAL BUS DEVICES Communication and bus line connection between microprocessor (IC341) and devices below are checked. USB: ISP1760 (IC361) ETHERNET: LAN9217 (IC362) (YMC-700 model) NPGA: NPGA(IC351) SDIO I/F: TE4300PF (IC366) (YMC-700 model) 2: EEPROM DEVICES Communication and bus line connection between microprocessor (IC341) and EEPROM (IC344) are checked. 3: WiFi MODULE Communication and bus line connection between microprocessor (IC341) and WiFi module are checked. 4: VIDEO DEVICES Communication and bus line connection between microprocessor (IC341) and the following devices are checked. ADV7840: HDMI receiver/Video decoder (IC311) ADV7510: HDMI transmitter (IC321) 5: PWM DEVICES Communication and bus line connection between microprocessor (IC341) and PWM (IC376) are checked. 6: DSP DEVICES Communication and bus line connection between microprocessor (IC341) and DSP (IC371) are checked. 7: FPGA DEVICES Communication and bus line connection between microprocessor (IC341) and FPGA (IC331) are checked. 8: IR BLASTER DEVICES Communication and bus line connection between microprocessor (IC341) and IR BLASTER (IC383) are checked. OK : No error detected NG : An error is detected Example Example IR BLASTER: OK Example FPGA : OK Example WiFi : OK Example EEPROM : OK Example Result : OK Example Result : OK Example ADV7840 : OK ADV7510 : OK www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 47 YMC-700/YMC-500 YMC-700/YMC-500 –> T: DEVICE ACCESS CHECK 2 1: EXTERNAL BUS DEVICES IC361 : OK IC344 : OK IC376 : OK IC362 : OK IC311 : OK IC371 : OK IC351 : OK IC321 : OK IC331 : OK IC366 : OK IC383 : OK VOLUME: 25 AUDIO: – – VIDEO: – – –> U: SERIAL No 1: Display SerialNo xxxxxxxxx VOLUME: 25 AUDIO: – – VIDEO: – – T: DEVICE ACCESS CHECK 2 This menu is used to display the result of check by using “S. DEVICE ACCESS CHECK 1”. 1: EXTERNAL BUS DEVICES U: SERIAL No. This menu is used to display the serial number. 1: Display Serial No. The serial number of this unit is displayed. 2: Write Serial No by barcode reader Not applied to these models. OK : No error detected NG : An error is detected Example Example www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 48 YMC-700/YMC-500 YMC-700/YMC-500 –> V: TUNER 1: TUNER RANGE (LOWER) Tuning frequency:87.5MHz VOLUME: 25 AUDIO: TUNER VIDEO: – – V: TUNER This menu is used to check FM tuner. INPUT select: TUNER 1: TUNER RANGE (LOWER) The tuning frequency (87.5 MHz) is selected. 2: TUNER RANGE (UPPER) The tuning frequency (107.9 MHz) is selected. 3: TUNER RANGE (MIDDLE) The tuning frequency (98.1 MHz) is selected. 4: AUTO TUNING Auto tuning mode: 87.5 to 107.9 MHz, 0.2 MHz step Example Tuning frequency:87.5MHz Tuning frequency:107.9MHz Tuning frequency:98.1MHz Example Auto tuning mode: xxx.xMHz www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 49 YMC-700/YMC-500 YMC-700/YMC-500 44 43 42 41 40 39 38 37 36 35 34 33 32 31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 GND GND GND GND GND GND PF6 PF7 PF8 PF9 PF10 PF11 PF12 VDDEXT GND PF13 PF14 PF15 PP13 VDDINT PP12 PP11 PP10 PPI_CLK VDDEXT GND VDDRTC RTXI RTXO GND NMI RESET VDDEXT XTAL CLKIN GND GND GND VDDEXT VROUT0 VROUT1 GND GND GND Micoroprocessor IC341 AD91089ZSKBC 176 175 174 173 172 171 170 169 168 167 166 165 164 163 162 161 160 159 158 157 156 155 154 153 152 151 150 149 148 147 146 145 144 143 142 141 140 139 138 137 136 135 134 133 GND GND GND SCKE SMS VDDEXT GND CLKOUT VDDINT SRAS SCAS SWE SA10 BR ARDY AMS0 AMS1 AMS2 AMS3 VDDINT VDDEXT GND AOE ARE AWE ABE0 ABE1 ADDR1 ADDR2 ADDR3 ADDR4 VDDEXT GND VDDINT ADDR5 ADDR6 ADDR7 ADDR8 ADDR9 ADDR10 ADDR11 ADDR12 VDDEXT GND VDDEXT PF5 PF4 PF3 PF2 PF1 PF0 VDDINT SCK MISO MOSI GND VDDEXT DT1SEC DT1PRI TFS1 TSCLK1 DR1SEC DR1PRI RFS1 RSCLK1 VDDINT DT0SEC DT0PRI TFS0 GND VDDEXT TSCLK0 DR0SEC DR0PRI RFS0 RSCLK0 TMR2 TMR1 TMR0 VDDINT TX RX EMU TRST TMS TDI TDO GND 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60 61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80 81 82 83 84 85 86 87 88 GND GND GND GND VDDEXT TCK BMODE1 BMODE0 GND DATA15 DATA14 DATA13 DATA12 DATA11 DATA10 DATA9 DATA8 GND VDDEXT DATA7 DATA6 DATA5 VDDINT DATA4 DATA3 DATA2 DATA1 DATA0 GND VDDEXT BG BGH ADDR19 ADDR18 ADDR17 ADDR16 ADDR15 ADDR14 ADDR13 GND GND GND GND GND 89 90 91 92 93 94 95 96 97 98 99 100 101 102 103 104 105 106 107 108 109 110 111 112 113 114 115 116 117 118 119 120 121 122 123 124 125 126 127 128 129 130 131 132 PPI/GPIO L1 data memory JTAG test and emulation Voltage regulator L1 instruction memory Memory management unit Core/System bus interface Real time clock UART port IrDA® Serial port (2) DMA controller Boot ROM SPI port External port FLASH, SDRAM control Event controller/ Core timer Watch dock timer Timer0, Timer1, Timer2 ■ IC DATA IC341: AD91089ZSKBC (DIGITAL P.C.B.) Microprocessor * No replacement part available. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 50 YMC-700/YMC-500 YMC-700/YMC-500 Blackfin PF Ports SPORT0 Synchronous memory control Memory Interface PPI UART TMR Ports (Used as General Output Ports (TMR0 and PPI sync ports (PPI) ) Pin No. Port Name Function Name I/O Detail of Function 51 PF0 ADC_N_CS O AD converter chip select 50 PF1 3.3S_N_ON O +3.3S power supply control 49 PF2 EEPROM_N_CS O EEPROM chip select 48 PF3 BF_PPI_FIELD O GUI field signal 47 PF4 BANK_SEL1 O Flash memory bank select signal 46 PF5 PWS_N_ON I Front panel power switch 38 PF6 PWR_N_PDET I Sub trans power detection 37 PF7 REM I Front panel IR receiver 36 PF8 NPGA_INT I NPGA interrupt request 35 PF9 BANK_SEL0 O Flash memory bank select signal 34 PF10 PWR_RY_ON O Main trans relay control 33 PF11 EXTP1_N_OE O Extended ports 1 output Enable 32 PF12 – – – Pin No. Port Name Function Name I/O Detail of Function 79 TMR0 USB_N_RST O Front panel LED control 78 TMR1 BF_PPI_HS O PPI H-sync 77 TMR2 BF_PPI_VS O PPI V-sync Pin No. Port Name Function Name I/O Detail of Function 21 PPI_CLK BF_PPI_CLK I PPI input clock 22 PP10 BF_PPI[0-7] O PPI output data 23 PP11 24 PP12 25 VDDINT 26 PP13 27 PF15 28 PF14 29 PF13 Pin No. Port Name Function Name I/O Detail of Function 81 TX BF_UART_TX O UART Tx 82 RX BF_UART_RX I/O UART Rx Pin No. Port Name Function Name I/O Detail of Function 76 RSCLK0 – I (no use) 75 RFS0 – 74 DR0PRI – 73 DR0SEC – 72 TSCLK0 DIR_SCK I SPORT0 Tx SCLK input 69 TFS0 DIR_WCK I SPORT0 Tx FS input 68 DT0PRI B F _ S P O R T _ SDO O SPORT0 Tx data output 67 DT0SEC – O (no use) Pin No. Port Name Function Name I/O Detail of Function 65 RSCLK1 – I (no use) 64 RFS1 – 63 DR1PRI – 62 DR1SEC – 61 TSCLK1 – 60 TFS1 – 59 DT1PRI – O (no use) 58 DT1SEC – Pin No. Port Name Function Name I/O Detail of Function 121 ADDR19 – O Address bus for async/Sync access 122 ADDR18 123 ADDR17 124 ADDR16 125 ADDR15 126 ADDR14 127 ADDR13 135 ADDR12 – O Address bus for async/Sync access 136 ADDR11 137 ADDR10 138 ADDR9 139 ADDR8 140 ADDR7 141 ADDR6 142 ADDR5 146 ADDR4 – O Address bus for async/Sync access 147 ADDR3 148 ADDR2 149 ADDR1 98 DATA15 – I/O Data bus for async access 99 DATA14 100 DATA13 101 DATA12 102 DATA11 103 DATA10 104 DATA9 105 DATA8 108 DATA7 – I/O Data bus for async access 109 DATA6 110 DATA5 112 DATA4 – I/O Data bus for async access 113 DATA3 114 DATA2 115 DATA1 116 DATA0 150 ABE1 – O Byte enables/Data masks for async/Sync access 151 ABE0 163 BR – I Bus request (This pin should be pulled HIGH if not used.) 119 BG – O Bus grant 120 BGH – O Bus grant hang www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 51 YMC-700/YMC-500 YMC-700/YMC-500 Asynchronous memory control Asynchronous memory control JTAG port SPI port Pin No. Port Name Function Name I/O Detail of Function 158 AMS3 – O Banks select 159 AMS2 160 AMS1 161 AMS0 162 ARDY – I hardware ready control (This pin should be pulled HIGH if not used.) 154 AOE – O Output enable 153 ARE – O Read enable 152 AWE – O Write enable Pin No. Port Name Function Name I/O Detail of Function 167 SRAS – O Row address strobe 166 SCAS – O Column address strobe 165 SWE – O Write enable 173 SCKE – O Clock enable 169 CLKOUT – O Clock output 164 SA10 – O A10 pin 172 SMS – O Bank select Pin No. Port Name Function Name I/O Detail of Function 94 TCK – I JTAG clock 87 TDO – O JTAG serial data out 86 TDI – I JTAG serial data in 85 TMS – I JTAG mode select 84 TRST – I JTAG reset (This pin is should be pulled LOW if JTAG is not used.) 83 EMU – O Emulation output Pin No. Port Name Function Name I/O Detail of Function 55 MOSI – I/O Master out slave in 54 MISO – I/O Master in slave out (This pin is should be pulled HIGH through a 4.7 k-ohms resistor if booting via the SPI port.) 53 SCK – I/O SPI clock Real-time clock Clock Mode controls Voltage regulator Pin No. Port Name Function Name I/O Detail of Function 17 RTXI – O RTC crystal output 16 RTXO – I RTC crystal input (This pin should be pulled LOW when not used.) Pin No. Port Name Function Name I/O Detail of Function 10 CLKIN – I Clock/Crystal input (This pin needs to be at a level or clocking.) 11 XTAL – O Crystal output Pin No. Port Name Function Name I/O Detail of Function 13 RESET – I Reset (This pin is always active during core power-on.) 14 NMI – I Nonmaskable interrupt (This pin should be pulled LOW when not used.) 95 BMODE1 – I Boot mode strap (These pins must be pulled to the state required for the desired boot mode.) 96 BMODE0 – Pin No. Port Name Function Name I/O Detail of Function 4 VROUT1 – O External FET drive 5 VROUT0 – www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 52 YMC-700/YMC-500 YMC-700/YMC-500 Pin No. Port Name Function Name I/O Detail of Function 1 GND – G External ground 2 3 7 8 9 15 19 30 39 40 41 42 43 44 56 70 88 89 90 91 92 97 106 117 128 129 130 131 132 133 144 155 170 174 175 176 Supplies Pin No. Port Name Function Name I/O Detail of Function 6 VDDEXT – P I/O power supply 12 20 31 45 57 71 93 107 118 134 145 156 171 52 VDDINT – P Core power supply 66 80 111 143 157 168 18 VDDRTC – P Real-time clock power supply www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 53 YMC-700/YMC-500 YMC-700/YMC-500 Pin No. Port Name Function Name Detail of Function 3 PIO[0] HTX_N_INT HDMI Tx interrupt 4 PIO[1] DAMP_N_SD DAMP shutdown 5 PIO[2] DIR_N_INT DIR interruption 6 PIO[3] DSP_N_INT DSP interruption 7 PIO[4] HRX_INT1 HDMI Rx interrupt 1 24 PIO[5] SDIO_N_INT SDIO interface interrupt 31 PIO[6] WIFI_ACTIVE WiFi active 35 PIO[7] HRX_N_INT3 HDMI Rx interrupt 3 36 PIO[8] BF_SPTX_WCK Blackfin sport word clock 61 PIO[9] MIC_N_DET MIC detect 62 PIO[10] HRX_N_INT2 HDMI Rx interrupt 2 63 PIO[11] USB_N_INT USB interrupt 64 PIO[12] VOL_RA Rotary encoder input A 67 PIO[13] VOL_RB Rotary encoder input B 68 PIO[14] ETHER_N_INT Ethernet controller interruption 120 PIO[15] DAMP_N_OTW DAMP over temperature warning 13 PIO[16] EXTP2_N_OE Extended output ports 2 output enable 14 PIO[17] AD_N_RST Audio AD converter reset 15 PIO[18] DIR_N_RST DIR reset 16 PIO[19] HRX_N_RST HDMI Rx reset 17 PIO[20] HTX_PD HDMI Tx power down 20 PIO[21] (no use) 21 PIO[22] ETHER_N_RST Ethernet controller reset 22 PIO[23] DSP_N_RST DSP reset 39 PIO[24] VSEL_COMP Video input selector 52 PIO[25] VSEL_N_MUTE Video input selector 53 PIO[26] FPGA_CDONE FPGA config done 56 PIO[27] FPGA_N_STA FPGA status 119 PIO[28] – – 121 PIO[29] – – 123 PIO[30] – – 125 PIO[31] – – Pin No. Port Name Function Name Detail of Function 99 PO[0] ADC_SEL_A AD converter input select signal A 94 PO[1] ADC_SEL_B AD converter input select signal B 97 PO[2] ADC_SEL_C AD converter input select signal C 98 PO[3] IRB_N_RST IR blaster reset 51 PO[4] RDS_RST RDS reset 60 PO[5] RDS_CLK RDS clock 72 PO[6] – (no use) PIO[31:0] PO[6:0] • Microprocessor NPGA select port IC351: MB87L8760 (DIGITAL P.C.B) NPGA www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 54 YMC-700/YMC-500 YMC-700/YMC-500 Pin No. Port Name Function Name Detail of Function 8 PWM[0] LED1_ON Front panel LED control 23 PWM[1] LED2_ON Front panel LED control Pin No. Port Name Function Name Detail of Function 109 PI[0] DSP_N_IFO DSP information 111 PI[1] 5TUNER_N_STEREO Tuner stereo 77 PI[2] 5TUNER_N_TUNED Tuner tuned 80 PI[3] DSP_SPI_N_RDY DSP SPI ready 50 PI[4] 5RDS_DATA RDS data 59 PI[5] 5RDS_RDY RDS ready 71 PI[6] DIAG_N_DET Diag mode detection PI[6:0] PWM[6:0] www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 55 YMC-700/YMC-500 YMC-700/YMC-500 1 OE 2 D0 D1 D2 D3 D4 D5 D6 D7 3 4 5 6 7 20 Vcc 19 18 17 16 15 14 8 9 10 13 12 Q7 Q6 Q5 Q4 Q3 Q2 Q1 Q0 11 CP GND Extended Ports 2 are accessed using NPGA Extended strobe function. NPGA must be initialized before using EXT Ports 2 • Microprocessor extended port 1 Pin No. Port Name Function Name Detail of Function 1 OE /EXPE Extended port enable 2 D0 D00 Data bus 00 3 D1 D01 Data bus 01 4 D2 D02 Data bus 02 5 D3 D03 Data bus 03 6 D4 D04 Data bus 04 7 D5 D05 Data bus 05 8 D6 D06 Data bus 06 9 D7 D07 Data bus 07 10 GND DGND Ground of external 11 CP – – 12 7Q – – 13 6Q WIFI_N_RST WiFi module reset 14 5Q DIR_N_CS DIR chip select 15 4Q DSP_N_CS DSP chip select 16 3Q DSP_MT DSP mute 17 2Q FPGA_SPI_N_CS FPGA SPI chip select 18 1Q SDIO_N_RST SDIO interface reset 19 0Q NPGA_N_RST NPGA reset 20 VCC VCC Power supply +3.3V IC353: 74LVC574APW (DIGITAL P.C.B.) Octal D type flip flop with 5 V tolerant inputs/outputs positive edge trigger 3-state www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 56 YMC-700/YMC-500 YMC-700/YMC-500 1 2 3 4 5 6 7 8 9 10 20 19 18 17 16 15 14 13 12 11 OE 1D 2D 3D 4D 5D 6D 7D 8D GND VCC 1Q 2Q 3Q 4Q 5Q 6Q 7Q 8Q CLK OE 1 11 2 19 CLK 1D C1 1D 1Q 9 12 8D C8 8D 8Q Pin No. Port Name Function Name Detail of Function 1 OE /EXPE Extended port enable 2 1D D00 Data bus 00 3 2D D01 Data bus 01 4 3D D02 Data bus 02 5 4D D03 Data bus 03 6 5D D04 Data bus 04 7 6D D05 Data bus 05 8 7D D06 Data bus 06 9 8D D07 Data bus 07 10 GND DGND Ground of external 11 CLK NPGA_EXSTB Bank select 0 12 8Q 5TUNER_CS Tuner chip select 13 7Q 5PWM_N_PDN PWM modulator power down 14 6Q 5TUNER_MT Tuner mute 15 5Q 5PWM_N_MT Digital AMP mute 16 4Q 5PRE_SW_N_MT Subwoofer mute 17 3Q 5PWM_N__RST PWM modulator reset 18 2Q 5ISEL_B Audio input selector 19 1Q 5ISEL_A Audio input selector 20 VCC VCC Power supply +5V IC354: SN74AHCT574PWR (DIGITAL P.C.B.) Octal edge-triggered D-type flip-flops with 3-state outputs www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 57 YMC-700/YMC-500 YMC-700/YMC-500 1 OE 2 D0 D1 D2 D3 D4 D5 D6 D7 3 4 5 6 7 20 Vcc 19 18 17 16 15 14 8 9 10 13 12 Q7 Q6 Q5 Q4 Q3 Q2 Q1 Q0 11 CP GND Pin No. Port Name Function Name Detail of Function 1 OE /EXPE Extended port enable 2 D0 D00 Data bus 00 3 D1 D01 Data bus 01 4 D2 D02 Data bus 02 5 D3 D03 Data bus 03 6 D4 D04 Data bus 04 7 D5 D05 Data bus 05 8 D6 D06 Data bus 06 9 D7 D07 Data bus 07 10 GND DGND Ground of external 11 CP – – 12 7Q IR_N_PASS IR pass through control 13 6Q FPGA_N_CFG FPGA nConfig 14 5Q ETHER_FSEL Ethernet controller FIFO selector 15 4Q AD_HDMI_OE HDMI audio up-conversion output enable 16 3Q HRX_HPDC HDMI RX HPD for port C 17 2Q HRX_HPDB HDMI RX HPD for port B 18 1Q HRX_HPDA HDMI RX HPD for port A 19 0Q HTX_5V_PON HDMI Tx 5V power control 20 VCC VCC Power supply +3.3V • Microprocessor extended port 2 IC356: 74LVC574APW (DIGITAL P.C.B.) Octal D type flip flop with 5 V tolerant inputs/outputs positive edge trigger 3-state www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 58 YMC-700/YMC-500 YMC-700/YMC-500 Microcontroller I/F Cbit, Pc Fs calculator 1 13 48 2 47 28 27 46 45 44 32 34 40 CL CE DI DO RERR SDIN RDATA RMCK RBCK RLRCK SBCK SLRCK XMODE AUDIO INT CKST MOUT GPIO0 GPIO1 GPIO2 GPIO3 RXOUT2 RXOUT1 RX0 RX1 RX2 RX3 RX4 RX5 RX6 LPF XIN XOUT XMCK 41 39 38 37 36 24 21 4 8 10 29 9 5 3 16 22 17 20 23 35 33 Input Selector PLL Oscillation Amplifier Clock Selector Clock Divider Demodulation & Lock detect Data Selector 36 35 34 33 32 31 30 29 28 27 26 25 13 14 15 16 17 18 19 20 21 22 23 24 1 2 3 4 5 6 7 8 9 10 11 12 48 47 46 45 44 39 38 37 43 42 41 40 RBCK AVDD AGND RMCK DGND RXOUT1 RX0 RX1 RX2 RX3 DGND DVDD RX4 RX5 RX6 DVDD DGND DVDD RLRCK RDATA SBCK LC89058WD-E SDIN RERR INT CKST AUDIO MOUT DGND DVDD XIN XOUT XMCK DVDD DGND RXOUT2 GPIO3 GPIO2 GPIO1 GPIO0 DVDD DGND CL CE DI DO SLRCK LPF XMODE IC374: LC89058WD-E (DIGITAL P.C.B.) Digital audio interface receiver • Microprocessor DIR select port Pin No. Port Name Function Name I/O Detail of Function 1 RXOUT1 – O RX0-6 input S/PDIF through output pin 1 2 RX0 – l5(pd) 5V withstand voltage TIL input level compatible S/PDIF input pin (connected to GND when RX1 is set) 3 RX1 – I(pd) Co-axial compatible S/PDIF input pin (supported demodulation sampling frequency of up to 96 kHz) 4 RX2 – l5(pd) 5V withstand voltage TIL input level compatible S/PDIF input pin (connected to GND when RX1 is set) 5 RX3 – l5(pd) 5V withstand voltage TIL input level compatible S/PDIF input pin 6 DGND – Digital GND 7 DVDD – Digital power supply (3.3V) 8 RX4 – l5(pd) 5V tolerable TIL input level compatible S/PDIF input pin 9 RX5 – l5(pd) 5V tolerable TIL input level compatible S/PDIF input pin 10 RX6 – l5(pd) 5V tolerable TIL input level compatible S/PDIF input pin 11 DVDD – Digital power supply (3.3V) 12 DGND – Digital GND 13 LPF – O PLL loop filter connection pin 14 AVDD – Analog power supply (3.3V) 15 AGND – Analog GND 16 RMCK – O R system clock output pin (VCO, 512fs, XIN) 17 RBCK – O/I R system bit clock 1/0 pin (64fs) 18 DGND – Digital GND 19 DVDD – Digital power supply (3.3V) 20 RLRCK – O/I R system LR clock 1/0 pin (fs) 21 RDATA – O Serial audio data output pin 22 SBCK – O S system bit clock output pin (16fs, 32fs, 64fs, 128fs) 23 SLRCK – O S system LR clock output pin (fs/4, fs/2, fs, 2fs) 24 SDIN – l5 External serial audio data input pin 25 DGND – Digital GND 26 DVDD – Digital power supply (3.3V) 27 XMCK – O Oscillation amplifier clock output pin 28 XOUT – O Output pin connected to the resonator 29 XIN – I External clock input pin. connected to the resonator (12.288 MHz or 24.576 MHz) 30 DVDD – Digital power supply (3.3V) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 59 YMC-700/YMC-500 YMC-700/YMC-500 Pin No. Port Name Function Name I/O Detail of Function 31 DGND – Digital GND 32 MOUT – I/O Emphasis information II input fs monitor output II chip address setting input pin 33 AUDIO – I/O Channel status bit 1 output II chip address setting input pin 34 CKST – I/O Clock switching transition period signal output II master/slave setting input pin 35 INT – I/O Microprocessor interrupt signal output II pins 44-48 I/O setting input pin 36 RERR – O PLL lock error and data error flag output pin 37 DO – O CCB microprocessor I/F, read data output pin (3-state) 38 DI – l5 CCB microprocessor I/F, write data input pin 39 CE – l5 CCB microprocessor I/F, chip enable input pin 40 CL – l5 CCB microprocessor I/F, clock input pin 41 XMODE – l5 System reset input pin 42 DGND – Digital GND 43 DVDD – Digital power supply (3.3V) 44 GPIO0 AUDIO_SEL_A O Audio DSP input selector 45 GPI01 AUDIO_SEL_B O Audio DSP input selector 46 GPI02 HTX_AUDIO_SEL O HDMI TX output audio selector 47 GPI03 – O (no use) 48 RXOUT2 – O RX0-6 input S/PDIF through output pin 2 * Input voltage: 1= -0.3 to 3.6V, Is =-0.3 to 5.5V * Output voltage: 0= -0.3 to 3.6V * Pins 2, 4, 5, 8, 9, 10, 24, 38, 39, 40, and 41 have an internal pull-down resistor (Pd). Their level is fixed when they are unselected. * Pins 32 and 33 are input pins for chip address setting when pin 41 is held at the low level. * Pin 34 serves as the input pin for designating as the master or slave when pin 41 is held at the low level. * Pin 35 serves as the input pin for configuring the I/O of pins 44 to 47 when pin 41 is held at the low level. * The DVDD and AVDD pins must be held at the same level and turned on and off at the same timing to preclude latch- up conditions. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 60 YMC-700/YMC-500 YMC-700/YMC-500 IN1 IN2 IN3 MUX T/H VA 8-Bit SUCCESSIVE APPROXIMATION ADC GND IN4 GND SCLK CONTROL LOGIC CS DIN DOUT CS 1 VA 2 GND 3 IN4 4 IN3 5 SCLK ADC084S021 10 DOUT 9 DIN 8 IN1 7 IN2 6 Ohm 0 +2.2k +4.7k +8.2k +27.0k V 0 – 0.05 0.52 – 0.67 1.27 – 1.42 1.92 – 2.07 2.60 – 2.76 A/D value (3.3 V=255) 0 – 4 40 – 52 98 – 110 148 – 160 201 – 213 KEY1 (7 pin of IC381) 〈 (LEFT) 〈 (UP) 〉 (RIGHT) 〉 (DOWN) ENTER Ohm 0 +10.0k V 0 – 0.05 1.57 – 1.72 A/D value (3.3 V=255) 0 – 4 121 – 133 KEY2 (6 pin of IC381) CONTROL BACK Pin No. Port Name Function Name Detail of Function 1 CS /ADC_CS CS for microprocessor 2 VA +3.3S Power supply +3.3V 3 GND DGND Ground of external 4 IN4 Selector1 Connected to selector 1 5 IN3 PWR_PRV1 Power supply protection 1 6 IN2 KEY_INTPUT2 Front panel key 7 IN1 KEY_INTPUT1 Front panel key 8 DIN SPIMI Master output/slave input 9 DOUT SPIMO Master input/slave output 10 SCLK SPISCK SPI clock • Microprocessor ADC select port AD converter KEY1 KEY2 Destination detection for A/D port Pull-up resistance 10 k-ohms IC381: ADC084S021 CIMM (DIGITAL P.C.B.) 4-channel, 200 kSPS, 8-bit A/D converter www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 61 YMC-700/YMC-500 YMC-700/YMC-500 Y0 Y1 Y2 Y3 Y4 Y5 Y6 Y7 COM INH C B A 11 10 9 6 3 13 14 15 12 1 5 2 4 1 2 3 4 5 6 7 8 9 10 16 15 14 13 12 11 Y4 Y6 COM Y7 Y5 INH GND GND VCC Y2 Y1 Y0 Y3 A B C INPUTS ON CHANNEL INH L L L L L L L L H L L L H H H H X C L L H H L L H H X L H L H L H L H X L Y1 Y2 Y3 Y4 Y5 Y6 Y7 None Y0 B A DOCK type (15 pin of C382) Bluetooth iPod No connected A/D value (3.3 V=255) 5 – 25 120 – 140 250 – 255 Destination U Ohm (R3863 DIGITAL P.C.B.) 8.2 k Ohm (R3864 DIGITAL P.C.B.) 1 k V 0.27 – 0.44 Detection value 27 ±4 Model name YMC-700 YMC-500 Ohm (R3865 DIGITAL P.C.B.) 8.2 k 5.6 k Ohm (R3866 DIGITAL P.C.B.) 1 k 5.6 k V 0.27 – 0.44 1.57 – 1.72 Detection value 21 – 34 121 – 133 Pin No. Port Name Function Name Detail of Function 1 Y4 DC_PRT Digital AMP DC protection 2 Y6 DEST2 Destination 2 3 COM ADC_COM1 SPI bus COM (IC381) 4 Y7 DOCK_ID DOCK detection (Normal DOCK or Bluetooth adaptor) 5 Y5 DEST1 Destination 1 6 INH DGND Ground of external 7 GND DGND Ground of external 8 GND DGND Ground of external 9 C SELECT C ADC selector C 10 B SELECT B ADC selector B 11 A SELECT A ADC selector A 12 Y3 IP_DET iPod detection 13 Y0 DEST1 Destination detection 14 Y1 IP_AP iPod AP 15 Y2 DOCK_ID Dock ID 16 Vcc +3.3S Power supply +3.3V Selector1 IC382: SN74LV4051APWR (DIGITAL P.C.B.) 8-channel analog multiplexers/demultiplexers DOCK detection for AD port Pull-up resistance 10 k-ohms DEST1 Destination detection for A/D port DEST2 Model detection for A/D port www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 62 YMC-700/YMC-500 YMC-700/YMC-500 1 23 A AC A AC 1 23 50 75 76 1 51 25 26 100 52 1 53 105 156 157 104 208 8 4 1 1 44 45 89 88 132 133 176 8 4 1 1 10 20 1 27 54 28 25 48 1 24 1 7 14 1 3 4 5 65 102 38 1 103 128 64 39 50 75 76 1 51 25 26 100 1 36 37 72 73 108 109 144 1 12 13 24 25 36 37 48 14 7 1 1 5 10 1 4 8 1 4 8 1 4 8 5 1 1 7 1 2 3 54 1 28 27 ADV7840BBCZ-5 ADV7510BSTZ-225 EP2C8Q208C8N 74LVC3GU04DP AD91089ZSKBC LE25LA322M-TLM-E 74LVC245APW,118 K4S560832J-UC75000 K8P6415UQB-PI4B000 74LVC32APW 74LVC00APW 74LVC1G08GW 74LVC14APW MB87L8760 74LVC574APW ISP1760BE LAN9217-MT D70YE101BRFP266 74LVC3G04DP LC89058WD-E 74LVC125APW ADC084S021 CIMM BA4510F-E2 NE5532DR FA5511N-D1-TE1 BA00JC5WT-V5 BD9781HFP-TR LMV431AIMF 74LVC08APW M12L64164A-5TG ■ PIN CONNECTION DIAGRAMS • ICs www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 63 YMC-700/YMC-500 YMC-700/YMC-500 1 3 4 5 1 8 16 6 3 1 16 8 1 1 10 20 20 10 1 1 24 36 37 12 25 13 48 1 3 4 5 38 1 20 19 14 7 1 1 8 16 1 10 20 8 4 1 44 22 1 1 4 8 1 8 16 16 8 1 14 7 1 1: OUT 2: IN 3: COM 1: OUT 2: COM 3: IN 1: IN 2: GND 3: OUT 1: INPUT 2: GND 3: OUTPUT 3 2 1 8 4 1 1: REFERENCE 2: ANODE 3: CATHODE 1 2 3 1 5 3 1: VIN 2: ON/OFF control 3: VOUT 4: N.C. 5: GND NJM2386DL3-05 (TE1) NJM2867F3-05 R1172S181B-E2-F SN74LV157APWR R1172S121D-E2-F SN74LV123APWR SN74AHCT245PWR SN74AHCT574PWR TE4300PF R5523N001A-TR-F TAS5086DBT SN74LVU04APWR TC74VHC153FT PCM1803DBR SN74LV4051APWR NJM4565M (TE1) TAS5342LDDV NJM2904M (TE3) TC74HC4052AF TC74HC4053AF NJM2580M (TE2) R1172S331B-E2-F NJM79M05FA NJM78M12FA NJM78M05FA NJM7805FA TPS54331DR NJM431U www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 64 YMC-700/YMC-500 YMC-700/YMC-500 B E C C E B B C E E C B GD S IN COMMON OUT 1. Drain 2. Drain 3. Gate 4. Source 5. Drain 6. Drain 1 3 4 6 B E C B E C 2N5551S-RTK 2SA1576A 2SC2412K 2SC2705 2SC4488 2SD1938F 2SK3523-01R KRA104S-RTK KRC102S-RTK KRC104S-RTK KTC3875S RTQ040P02 2SA1015M Y 2SC4081 T106 Anode Cathode Anode Cathode Anode Cathode Anode Cathode 1 1 2 2: (No connect) 3 3 1 1 2 Anode Cathode Anode Cathode 1 2 3 Anode Cathode + AC AC – 2 Anode Cathode + – AC AC Anode Cathode ANODE CATHODE D1NL20U-5083 KDS160-RTK P6KE200ARL RB500V-40 S1NB20 1A 200V MAZ8047GLL 4.6V RB551V-30 SB01-05Q MAZ8030GLL 2.9V MAZ8051GML 5.1V MAZ8110GLL 10.7V MAZ8270GML 27.0V RB050L-40 SG20LC20USM 20.0A 1SS355 D1FK60-5063 D1FL20U-5063 D5SBA60 PD413PI2E00F RB051L-40 RB160L-40 TE25 UDZS3.3BTE-17 3.3V • Diodes • Transistors www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com YMC-700/YMC-500 65 MEMO MEMO w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com A B C D E F G H I J 1 2 3 4 5 6 7 66 YMC-700/YMC-500 MICRO- PROCESSOR AD91089Z IC341 NPGA MB87L8760 IC351 Flash Memory (8MB) MX29LV640DBTC-90GT IC344 AD CONVERTER AD CONVERTER PCM1803DBR IC375 HDMI RECEIVER Video Decoder ADV7840 M12L64164A-5TG IC311 HDMI IN 1 HDMI IN 2 I2S/DSD SPDIF COAXIAL IN AUDIO INPUT OPTICAL IN EEPROM LE25LA322 IC445 ADC084S021 IC381 SPI Bus Buffer 74LVC245APW IC441-IC444 (Up to 148.5MHz) Digital Video Data Bus 133MHz DIR LC89058W IC374 CB12 CB13 MAIN P.C.B. VIDEO/DOCK COMPONENT CB314 Analog In L/R CB385 PortA PortB P[35:0] I2C I2C Bus 36bit PJ371 U371 RX5 RX0 RX3 HDMI SPDIF SDIN SPORT0 Tx PWR_RY 34 38 37 PDET REM DOUT VIN PWR_PRV1 DEST U(8.2k/1k) DC_PRT MODEL 700(8.2k/1k)/ 500(5.6k/5.6k) KEY1,KEY2 REM IR_IN 16bit 16bit 16bit 16bit 16bit USB HOST ISP1760 IC361 Extended Ports 74LVC574FT SN74AHCT574FT 28bit IC353, 354, 356 8bit UART I2C0 I2C1 I2C2 UART0 UART1 UART2 SPI0 SPI1 SPI2 PIO USB CB362 SELECTOR1 SN74LV4051APWR IC382 SPI PPI EBIU 533MHz Ethernet LAN9217 ISP1760BE IC362 IC361 CB14 HDMI IN 3 PortC AIN11 AIN12 CVBS IN1 Cr Y Cb 16bit 16bit 16bit 16bit SDOUT CB361 NETWORK DIR/ADC HDMI Rx(I2S) BLACKFIN 8bit For MP3, AAC, WMA For GUI Output (480i,576i) MAIN P.C.B. 20MHz FPGA EP2C8Q208 Picture in Picture I to P conversion for GUI IC331 SDRAM IC332 16bit HDMI Rx(I2S) ADC SPI TMSD Port I2C SPI D[35:0] I2S DSD CVBS IN2 AIN1 AIN2 AIN3 SDIO I/F TE4300PF IC366 Wireless LAN module YMC-700 CB363 PortD SDRAM (64MB) 256Mbit(x8) 2pcs K4S560832J-UC75 IC342,343 AIN7 AIN8 AIN9 HDMI TRANSMITTER ADV7510 IC321 3.3V->5V SN74VHCT245 HDMI OUT CB321 36bit CB384 MAIN P.C.B. CB385 Power off during standby mode FM TUNER CB385 Data Line Control Line DSP TMS320D70Y IC371 SDRAM IC372 Flash Memory EN29LV160AB-70T K4S641632-UC60000 IC373 IR DATA 123MHz 16bit 16bit 16bit EBIU IR Blaster IC383 IC384 IC386 MAIN P.C.B. MAIN P.C.B. JK382 DOCK (iPod) JK381 PWM modulator TAS508 IC376 LED Driver LED Driver OPERATION P.C.B. REMOTE CONTROL OUT 1/2 REMOTE CONTROL OUT 3/IN CB385 IR Pass through XL381 8MHz 8 7 XL331 27MHz 9 8 XL311 28.63636MHz XL371 24.576MHz XL312 28.63636MHz XL362 12MHz 12 11 XL341 16.666MHz XL361 25MHz 10 12 5 6,7 2 1 6 5 38 24 5 1,2 9 2 21 11 IC323 IC472, 473 XL331 27MHz 129 23 29 28 UART learning Data out DIGITAL �����������������→ SCHEMATIC DIAGRAM ■ BLOCK DIAGRAMS DIGITAL P.C.B. Section Block Diagram YMC-700 YMC-500 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com A B C D E F G H I J 1 2 3 4 5 6 7 YMC-700/YMC-500 67 PWM DIR/DSP etc RST TAS5342L DIGITAL AMPLIFIER TAS5342L IC375 IC104 IC103 IC151 IC102 IC51 IC54 IC52 IC53 IC376 PCM1803 ADC DIGITAL AMPLIFIER TAS5342L SURROUND L/ CENTER SPEAKERS FRONT R/- DOCK (iPod) AUDIO IN OPTIMIZER MIC ANALOG INPUT SURROUND R/ FRONT L SUBWOOFER DIGITAL AMPLIFIER PWM modulator (VOL) TAS5086 Ch4-VOL Ch3-VOL Ch2-VOL Ch1-VOL Ch5-VOL ch6 processing PWM DC_PRT DC_PRT DC_PRT I2S I2S +3.3D ch1 – C DAMP_N_OTW DAMP_N_SD ch2 – SL ch3 – SR PWM_SD1 PWM_SD2 PWM_SD3 PWM_SCK PWM_BCK PWM_LRCK DIR_MCK 5A/3.3D +5A/-5A AD_N_RST DIR_WCK ISEL_A ADL/ADR ISEL_B DOCK_ID IP_DET IPAP_DET IPD_MISO IPD_MOSI TUN_N_CS, TUN_SCK, TUN_MOSI, TUN_MISO TUN_MUTE TUN_N_ST TUN_TUNED Selector INPUT SELECTOR TC74HC4052AF ANALOG AUDIO ANALOG VIDEO POWER SUPPLY FM TUNER in0 in1 in2 in3 Input Pin jack iPod Mic Tuner +10T MIC_N_DET +5I DG IE DIR_BCK DIR_SDIN PWM_SDA PWM_SCL PWM_N_RST PWM_N_PDN PWM_N_MUT ch4 – FL ch5 – FR ch6 – SW +12A +30A SW_FMT filter L.P.F. +7dB 2,5 2,5 2,5 7,15 1,2 4,11 9,10 14 2,15 1,12 3,13 7,15 7,15 6,16 6,16 6,16 COMP_Y Y Pb/Cb Pr/Pr Y Pb/Cb Pr/Cr VSEL_N_MUTE (VSEL_B) A/B/C VSEL_COMP (VSEL_A) COMP_CB COMP_CR CVBS1 CVBS2 W2001 Q2001 IC202 Q2002 IC201 POWERSAVE Video Amp NJM2580 To DIGITAL P.C.B. via CB103 Component IN1 Component IN2 DOCK (iPod) VIDEO IN CVBS 13 2 9,10,11 15 4 14 5 12 1 3 13 IPV INPUT SELECTOR 74HC4053 5 7 9 11 13 3 1 RY1 +30A AMP_GND IC14 IC15 +12A -5A AG IC6 +5A Q1 RY1 Power Detector Q2,3,5 MG PDET C5 D3 IC2 78M05 78M12 79M05 V 3. 6 + B1879D +3.3V IC8 TPS54331 IC5 BA00JC5W To DOCK (iPod) T1 +12A, +5A, -5A ,+5V +6.3V ,+2.5V, +5I, IGND +5I +2.5V To DIGITAL AMPLIFIER To ANALOG AUDIO PS protection (PWR_PRV1) AC IN TPS54331 78M05 MG +13V To DIGITAL P.C.B. To DIGITAL P.C.B. POWER TRANSFORMER D5 D5SBA50 D27 IC10 IC11 IC4 IC1 F1 TPS54331 IC12 +5V T2 PWR_RY Q4 D22 D23 D20 DIGITAL �����������������→ SCHEMATIC DIAGRAM MAIN �����������������→ SCHEMATIC DIAGRAM MAIN �����������������→ SCHEMATIC DIAGRAM MAIN �����������������→ SCHEMATIC DIAGRAM OPERATION ��������������→ SCHEMATIC DIAGRAM AUDIO/VIDEO/POWER SUPPLY Sections Block Diagram YMC-700 YMC-500 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com A B C D E F G H I J 1 2 3 4 5 6 7 68 YMC-700/YMC-500 IC382 IC366 IC351 IC442 IC441 IC346 IC347 IC373 IC375 IC345 CB381 IC374 IC383 IC361 IC363 IC378 CB362 CB361 JK381 JK382 IC379 CB321 CB313 CB312 CB311 IC352 IC344 IC343 IC341 IC331 IC321 IC311 IC326 IC447 IC349 IC353 IC354 IC356 IC444 IC362 IC334 IC443 B A H G J F D C POINT A XL311 (AC20 of IC311) POINT B XL312 (D22 of IC311) POINT C XL331 (Pin 1 of IC334) POINT D XL341 (Pin 10 of IC341) POINT F XL361 (Pin 38 of IC366) POINT G XL362 (Pin 11 of IC361) POINT J XL381 (Pin 7 of IC383) POINT H XL371 (Pin 29 of IC374) DIGITAL P.C.B. (Side A) OUT 1/2 IN 1 IN 2 IN 3 IN / OUT 3 REMOTE CONTROL USB NETWORK 1 COAXIAL 2 OPTICAL HDMI IN HDMI OUT No replacement part available. No replacement part available. YMC-700 YMC-700 YMC-700 GND 1 1 1 3 6 4 1 20 10 11 24 48 25 12 1 1 1 10 20 11 1 10 20 11 11 20 10 1 11 20 10 1 11 20 10 1 25 48 1 24 27 28 54 1 1 1 10 20 11 1 10 20 11 7 8 14 1 1 7 8 14 10 1 14 16 7 8 8 11 20 9 133 176 44 45 88 89 132 1 1 4 8 5 52 53 104 105 156 157 208 1 1 1 14 7 8 7 14 8 25 26 50 100 76 51 75 1 1 1 36 37 1 1 26 50 51 75 1 3 4 5 76 100 25 38 39 64 65 102 103 128 72 73 108 109 144 10 20 11 1 8 16 9 12 25 3637 48 13 24 1 11 12 22 23 33 34 44 13 24 25 36 37 48 IC374 GND GND RESET +2.5V +2.5V +3.3V +3.3V +5V +6V MAIN (W1) AUDIO IN 1 23 A AC ■ PRINTED CIRCUIT BOARDS • Semiconductor Location Ref No. Location D3101 H6 D3102 H6 D3103 H6 D3104 H6 D3105 H6 D3106 H6 D3107 H6 D3108 H6 D3109 G6 D3110 G6 D3111 G6 D3112 G6 D3113 G6 D3114 G6 D3115 G6 D3116 G6 D3117 G6 D3118 G6 D3119 G6 D3120 G6 D3121 G6 D3122 G6 D3123 G6 D3124 G6 D3215 H5 D3301 D4 D3402 F3 D3706 H4 D3804 C6 D3805 C6 D3806 C6 D3807 C6 D3808 C6 D3809 C6 Ref No. Location IC311 H6 IC321 F6 IC326 H5 IC331 G5 IC334 E5 IC341 E5 IC343 D4 IC344 D4 IC345 E4 IC346 E4 IC347 E4 IC349 E4 IC351 C5 IC352 C4 IC353 D5 IC354 D5 IC356 E5 IC361 D6 IC362 D6 IC363 D6 IC366 C4 IC373 G5 IC374 D4 IC375 H4 IC378 E6 IC379 E6 IC382 C3 IC383 C5 IC441 E4 IC442 E4 IC443 E5 IC444 E5 IC447 E3 Q3101 H6 Q3102 I6 Q3103 H6 Q3104 H6 Q3105 G6 Q3106 G6 Q3801 D6 Q3802 C6 Q3803 C6 Q3807 D4 YMC-700 YMC-500 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com A B C D E F G H I J 1 2 3 4 5 6 7 YMC-700/YMC-500 69 IC324 IC323 IC371 IC472 IC473 IC471 CB385 CB382 IC445 IC474 IC342 IC384 IC449 IC478 IC327 IC332 CB363 CB383 IC333 IC348 IC385 IC365 IC448 CB384 IC376 IC381 IC386 IC448 IC372 E 1 R4429 (+3.3EX) (13 pin) IC341 2 POWER ON POWER OFF 1 R4429 (+3.3EX) (13 pin) IC341 2 POWER OFF POINT E 1 / R4429 (+3.3EX), 2 / Pin 13 of IC341 POWER ON 1 R4429 (+3.3EX) (13 pin) IC341 2 1 2 MAIN (CB101) MAIN (W2001) OPERATION (2) (CB154) MAIN (CB50) WIFI (CB601) YMC-700 5TUN_N_CS COMP_Y COMP_CR COMP_CB CVBS CVBS2 GND GND GND GND GND 5TUN_MOSI 5TUN_SCK 5TUN_MISO 5TUN_MUTE 5TUN_N_ST 5TUN_TUNED 5VSEL_COMP 5VSEL_N_MUTE AG AG AG 5ISEL_B 5ISEL_A RDS_RST RDS_CLK RDS_RDY RDS_RXS GND GND SW_N_MT DC_PRT PWR_PRV1 PWM_N_6 PWM_6 PWM_1 PWM_2 PWM_3 PWM_4 PWM_5 DAMP_N_OTW DAMP_N_SD DIAG_N_DET PWR_N_PDET PWR_RY VALID1 VALID2 3.3S_ON GND GND GND GND GND GND GND GND +5V +5V SD_D3 SD_D2 SD_D1 SD_D0 SD_CMD SD_CLK WL_ACTIVE GND GND GND RESET MIC_N_DET PSW LED1 LED2 REM REM+ REM- DG DG +3.3M +3.3D KEY1 KEY2 +5D VOL_RB VOL_RA IR_DATA ADR ADL DOCK_ID GND IPAP_DET IP_DET IPD_MISO IPD_MOSI GND DIGITAL P.C.B. (Side B) No replacement part available. 1 16 9 1 7 14 8 1 7 14 8 8 1 1 3 27 3637 1 28 4 6 54 72 73 108 109 144 1 5 4 8 1 5 4 1 10 20 11 14 1 8 7 5 8 1 4 20 38 19 1 1 3 6 4 8 1 5 4 1 3 4 5 1 3 4 5 1 3 4 5 1 1 3 4 5 1 1 5 10 6 5 5 27 1 8 1 3 6 4 1 7 14 8 1 27 28 54 54 28 YMC-700 YMC-700 • Semiconductor Location Ref No. Location D3125 H6 D3126 H6 D3127 H6 D3128 G6 D3129 G6 D3130 G6 D3131 F6 D3132 F6 D3133 F6 D3209 F6 D3210 F6 D3211 G6 D3212 F6 D3213 E6 D3214 F6 D3216 H6 D3217 E6 D3219 E6 D3303 E4 D3404 E4 D3601 B3 D3602 B3 D3705 H4 D3801 C3 D3802 C6 D3810 B3 D3812 C3 D3813 B4 Ref No. Location IC323 F6 IC324 F6 IC327 E6 IC332 F4 IC333 F4 IC342 C4 IC348 D4 IC365 B4 IC371 G4 IC372 G5 IC376 D3 IC381 C3 IC384 C4 IC385 D3 IC386 C6 IC445 E5 IC446 E4 IC448 D4 IC449 C4 IC450 D5 IC471 H4 IC472 F4 IC473 F3 IC474 D4 IC478 D4 Q3401 E4 Q3804 C6 Q3805 C6 YMC-700 YMC-500 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com A B C D E F G H I J 1 2 3 4 5 6 7 70 YMC-700/YMC-500 W1603A SW161 CB172 W1602 CB171 W1851 W1603B W1601A W1601B CB151 CB152 SW191 CB154 CB153 JK151 OPERATION (1) P.C.B. (Side A) OPERATION (4) P.C.B. (Side A) OPERATION (5) P.C.B. (Side A) OPERATION (6) P.C.B. (Side A) OPERATION (2) P.C.B. (Side A) OPERATION (3) P.C.B. (Side A) STANDBY/ON CONTROL YPAO MIC BACK VOLUME POWER indicator (left side) POWER indicator (right side) ENTER NC REM PSW_N_ON LED1 LED2 REM +3.3M REM+ REM- DG +3.3D +5D VOL_RB VOL_RA IR_DATA NC PSW_N_ON LED1 LED2 REM +3.3M REM+ REM- DG +3.3D +5D VOL_RB VOL_RA IR_DATA NC +3.3M +3.3D IR_DATA REM+ REM- DG PHD PHD DG DG DG (UP) (LEFT) (RIGHT) (DOWN) +3.3M KEY1 KEY2 DG +3.3M KEY1 KEY2 NC REM +3.3M +3.3D IR_DATA REM+ REM- DG PHD PHD DG DG PSW_N_ON DG PSW_N_ON DG E -5A E MIC +5A MAIN (W1000) DIGITAL (CB383) MIC_N_DET PSW LED1 LED2 REM REM+ REM- DG NC +3.3M +3.3D KEY1 KEY2 +5D VOL_RB VOL_RA IR_DATA • Semiconductor Location Ref No. Location D1601 D3 D1602 B3 D1701 H6 D1703 B6 YMC-700 YMC-500 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com A B C D E F G H I J 1 2 3 4 5 6 7 YMC-700/YMC-500 71 IC161 IC151 IC171 OPERATION (1) P.C.B. (Side B) OPERATION (4) P.C.B. (Side B) OPERATION (5) P.C.B. (Side B) OPERATION (6) P.C.B. (Side B) OPERATION (2) P.C.B. (Side B) OPERATION (3) P.C.B. (Side B) 1 4 8 5 8 1 5 4 5 8 4 1 Ref No. Location D1501 H3 D1502 H2 D1503 I2 D1603 B3 D1702 B6 D1704 B2 IC151 I3 IC161 A3 IC171 B6 Q1601 B3 Q1602 D3 Q1603 D3 Q1604 B3 Q1701 B3 • Semiconductor Location YMC-700 YMC-500 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com A B C D E F G H I J 1 2 3 4 5 6 7 72 YMC-700/YMC-500 IC53 IC52 IC51 W1 CB50 IC54 IC202 W2001 W1000 IC103 IC104 IC6 IC55 IC5 IC12 IC8 IC14 IC15 IC7 IC13 IC10 IC11 IC4 IC1 IC3 IC2 IC201 CB101 IC102 CB100 MAIN P.C.B. (Side A) TUN_N_CS TUN_N_SCK TUR TUL TUN_N_ST +10T NC TUN_N_MOSI TUN_N_MISO TUE TUN_MUTE TUN_N_TUNED COMP_RDS FM TUNER DIGITAL (CB385) DIGITAL (CB381) DIGITAL (CB384) DIGITAL (CB382) 5TUN_N_CS 5TUN_MOSI 5TUN_SCK 5TUN_MISO 5TUN_MUTE 5TUN_N_ST 5TUN_TUNED 5VSEL_COMP 5VSEL_N_MUTE AG AG AG 5ISEL_B 5ISEL_A RDS_RST RDS_CLK RDS_RDY RDS_RXS ADR ADL DOCK_ID GND IPAP_DET IP_DET IPD_MISO IPD_MOSI GND OPERATION (2) (CB151) E -5A E MIC +5A MAIN P.C.B. (Side A) CENTER SURROUND FRONT R L R L 3 SUB WOOFER Cr/Pr Cb/Pb Y DOCK AC IN No replacement part available. COMP_Y COMP_CR COMP_CB CVBS CVBS2 GND GND GND GND GND GND GND GND RESET +2.5V +2.5V +3.3V +3.3V +5V +6V R L OUTPUT VIDEO IN 1/2 SPEAKERS AUDIO IN 3 VIDEO IN GND SW_N_MT DC_PRT PWR_PRV1 PWM_N_6 PWM_6 PWM_1 PWM_2 PWM_3 PWM_4 PWM_5 DAMP_N_OTW DAMP_N_SD DIAG_N_DET PWR_N_PDET PWR_RY VALID1 VALID2 3.3S_ON GND GND GND GND GND GND GND GND 1 4 8 1 2 3 4 1 2 3 4 8 1 4 5 5 1 4 8 5 1 22 44 23 1 22 44 23 1 22 44 23 1 4 8 5 9 16 8 1 8 9 16 14 7 1 1 8 8 1 4 5 5 8 1 4 1 4 8 5 1 1 IN OUT CON IN OUT CON IN OUT CON IN 1 3 3 1 1 5 OUT CON 7 4 8 5 • Semiconductor Location Ref No. Location D1 D5 D2 D5 D3 D5 D5 C6 D6 D5 D7 D6 D11 D6 D14 E7 D15 E6 D17 E6 D19 F5 D20 G6 D21 E5 D27 F7 D28 F6 D30 G6 D31 F5 D32 F5 D33 G5 D34 G6 D35 G6 D1000 H3 D1003 G4 D1004 G4 IC1 E6 IC2 E6 IC3 E6 IC4 E5 IC5 G7 Ref No. Location IC6 F5 IC7 F6 IC8 G6 IC10 F5 IC11 F5 IC12 G5 IC13 F6 IC14 G6 IC15 G6 IC51 E4 IC52 E4 IC53 D4 IC54 F3 IC55 F5 IC102 F2 IC103 G4 IC104 F4 IC201 G3 IC202 G3 Q1 D5 Q2 D5 Q3 D5 Q4 D7 Q500 F3 Q501 F2 Q502 F2 Q1000 H3 Q2001 G2 Q2002 G3 YMC-700 YMC-500 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com A B C D E F G H I J 1 2 3 4 5 6 7 YMC-700/YMC-500 73 MAIN P.C.B. (Side B) MAIN P.C.B. Ref No. Location D4 C5 D8 D5 D9 D5 D10 D7 D12 D5 D16 E7 D18 E7 D22 F6 D23 F6 D25 E5 D29 E5 D1001 G4 D1002 G4 D2503 G2 Q5 D5 Q11 E5 Q12 E5 • Semiconductor Location YMC-700 YMC-500 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com A B C D E F G H I J 1 2 3 4 5 6 7 74 YMC-700/YMC-500 CB601 IC601 IC602 WIFI P.C.B. (Side A) DIGITAL (CB363) GND +5V +5V SD_D3 SD_D2 SD_D1 SD_D0 SD_CMD SD_CLK WL_ACTIVE GND GND GND RESET 1 1 3 6 4 12 13 24 25 36 37 48 No replacement part available. WIFI P.C.B. (Side B) Ref No. Location D6001 C3 IC601 C4 IC602 C3 • Semiconductor Location YMC-700 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com ★ All voltages are measured with a 10MΩ/V DC electronic voltmeter. ★ Components having special characteristics are marked ⚠ and must be replaced with parts having specifications equal to those originally installed. ★ Schematic diagram is subject to change without notice. A 1 2 3 4 5 6 7 8 9 10 B C D E F G H I J K L M N 75 DIGITAL 1/8 YMC-700/YMC-500 SCHEMATIC DIAGRAMS IC311 IC311 IC311 IC311 IC311 CB313 CB312 CB311 POINT A XL311 (AC20 of IC311) POINT B XL312 (D22 of IC311) A B 0.5 0.5 0.6 0.6 0.5 0.6 0.5 0.5 0 0 0 0 0 0 0 0 0.6 0 0.6 0 0 0 0 0 0 0 0 0 0.3 0.9 0 0 0 0 0 0 0 0 0 1.7 0 3.3 3.3 3.3 0 0 0 0 3.3 0 0 0 0 0 0 0 0 0 0 3.3 0 0 0 0 0 0 0 0 0 0 0 0 3.3 0 0 1.8 1.8 1.8 1.8 1.8 1.8 1.8 1.8 1.8 1.8 1.8 1.8 1.8 1.8 1.8 1.8 1.8 1.8 3.3 3.3 3.3 3.3 3.3 3.3 3.3 3.3 3.3 3.3 1.8 1.8 1.8 1.8 1.8 1.8 1.8 1.8 1.8 1.8 1.8 1.8 1.8 1.8 1.8 1.8 3.3 3.3 3.3 3.3 3.3 3.3 3.3 3.3 3.3 3.3 3.3 3.3 3.3 3.3 3.3 3.3 3.3 3.3 3.3 3.3 3.3 1.8 1.8 1.8 1.8 1.8 1.8 1.8 1.8 3.3 3.3 0 0 0 0 0 0 0 0 3.3 0 0 0 0 0 0 0 0 0.2 0 0 0.2 0.5 0.7 0.9 1.3 0 0 0 0.6 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0.5 0 0 1.3 0.6 0.9 0.8 1.3 1.7 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0.6 0 0 0 0 0 0 0 0 DIGITAL IN OUTPUT FORMATTER IC311: ADV7840BBCZ-5 12-bit, 170 MHz video and graphics digitizer with 3D comb filter decoder and quad HDMI 1.3 receiver INT1 STANDARD DEFINITION PROCESSOR (SDP) LLC P24 TO P35 P12 TO P23 P0 TO P11 HS VS/FIELD DE/FIELD SYNC_OUT/INT2 INT3 CVBS YC RGB FB CVBS OUT SYNC1 SYNC2 HS_IN1 VS_IN1 VS_IN2/TRI5 VS_IN2/TRI6 SCL SDA CEC AV_LINK RXA_C RXB_C RXC_C RXD_C RXA_0 RXA_1 RXA_2 RXB_0 I2S0 I2S1 I2S2 I2S3 SCLK MCLKOUT SPDIF LRCLK RXB_1 RXB_2 RXC_0 RXC_1 RXC_2 RXD_0 RXD_1 RXD_2 DDCA_SDA DDCA_SCL DDCB_SDL DDCD_SCL DDCC_SCL DDCD_SDA DDCC_SDA DDCB_SDA TRI4 TRI1 TO FUNCT1 SCART RGB YPrPb DAC ADC0 CLAMP ANALOG FRONT END 12- CHANNEL INPUT MATRIX COLOR SPACE CONVERTER DECIMATION AND DOWNSAMPLING FILTERS EMBEDDED SYNC (A) (B) (C) (A) (B) (C) (A) (B) (C) (D) TBC LTI 3D CORE TRI-LEVEL SLICER AVLINK CONTROLLER LLC GENERATION CONTROL CONTROL AND DATA CONTROL INTERFACE I2C SYNC PROCESSING AND CLOCK GENERATION 12 ADC1 CLAMP 12 ADC2 DATA PROCESSOR CLAMP 12 ADC3 CLAMP 12 CEC CONTROLLER MUX MUX PLL DATA REC OVERY ALIGNMENT HDMI DECODE FILTER XCR 4:4:2 TO 4:4:4 CONVER- SION DE HS VS HDCP ENGINE CONTROLLER HDCP EEPROM PACKET PROCESSOR EQUAL- IZER CONTROL MUX HS/CS,VS SAMPLER EQUAL- IZER SAMPLER EQUAL- IZER SAMPLER EQUAL- IZER SAMPLER 2D CORE ITOP CTI STANDARD AUTODETECTION MACROVISION DETECTION DDR/SDR-SDRAM INTERFACE COLORSPACE CONVERSION FAST BLANK OVERLAY CONTROL VERTICAL PEAKING HORIZONTAL PEAKING COMPONENT PROCESSOR DIGITAL PROCESSING BLOCK VIDEO DATA PROCESSOR GAIN CONTROL MACROVISION AND CGMS DETECTION SYNC SOURCE AND POLARITY DETECT ACTIVE PEAK AND HSYNC DEPTH NOISE AND CALIBRATION VSI DECODER FAST I2C INTERFACE I2C READ BASS ANCILLARY DATA ANCILLARY DATA FORMATTER PACKET/ INFOFRAME MEMORY AUDIO PROCESSOR DIGITAL FINE CLAMP PROGRAM MABLE DELAY OFFSET ADDRESS CP CSC AV CODE INSERTION SYNC EXTRACT 12 12 12 STANDARD IDENTIFICATION HDMI IN No replacement part available. No replacement part available. No replacement part available. No replacement part available. to DIGITAL 4/8 to DIGITAL 5/8 to DIGITAL 8/8 to DIGITAL 5/8 to DIGITAL 5/8 to DIGITAL 2/8 to DIGITAL 5/8 YMC-500 YMC-700 to DIGITAL 3/8 to DIGITAL 3/8 to DIGITAL 5/8 to DIGITAL 5/8 to DIGITAL 2/8, 7/8 HDMI RECEIVER HDMI RECEIVER HDMI RECEIVER No replacement part available. HDMI RECEIVER HDMI RECEIVER w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com ★ All voltages are measured with a 10MΩ/V DC electronic voltmeter. ★ Components having special characteristics are marked ⚠ and must be replaced with parts having specifications equal to those originally installed. ★ Schematic diagram is subject to change without notice. A 1 2 3 4 5 6 7 8 9 10 B C D E F G H I J K L M N YMC-700/YMC-500 76 DIGITAL 2/8 CB321 IC324 IC325 IC321 IC323 IC327 IC326 3.3 6.2 5.1 5.1 5.1 0 1.8 0 2.5 1.8 2.5 0 2.5 3.3 1.8 1.9 0 2.5 1.9 2.5 3.3 0.6 1.7 1.7 1.7 1.7 1.7 0 3.7 0 1.3 1.7 1.7 1.7 1.7 0 0 2.5 3.3 1.9 0 5.1 5.1 0 1.9 0 3.3 0 3.3 0 3.0 3.0 0.9 3.0 3.0 0 0 3.0 3.0 3.0 0 4.3 0 1.9 1.9 0.6 1.9 3.0 1.9 1.9 0 0 1.9 0 1.9 0 1.7 0 0 1.3 1.7 1.7 0 0 0 0 0 0 3.3 1.9 0 0 1.7 3.3 3.0 3.1 0.3 0.4 0 0.3 0.3 0.4 0 0 0 0 0 0.4 0.2 0.5 3.2 0.3 0.2 0 1.9 1.9 0.4 1.7 0.4 0 0 0 0 3.0 0.4 0.3 0.3 1.3 0.4 0 0 0 0 0 0 2.5 3.1 0 0 ANALOG IN DIGITAL IN IC321: ADV7510BSTZ-225 Low power HDMI 1.3 compliant transmitter Audio Data Capture 4:2:2 4:4:4 and Color Space Converter Registers and Config. Logic HDCP and EDID Micro- processor S/PDIF MCLK LRCLK SCLK DSD_CLK DSD[5:0] D[35:0] VSYNC HSYNC DE CLK HPD INT SDA SCL I2S[3:0] I2C Slave I2C Master TMDS Outputs HDCP Encryption HDCP Keys CEC Controller/ Buffer Video Data Capture CEC Tx0 Tx1 Tx2 TxC DDCSDA DDCSCL VOUT VIN Control GND 1 4 5 2 IC324: NJM2867F3-05 Low dropout voltage regulator Bandgap Reference Thermal Protection IC326, 327: R1172S181B-E2-F Voltage regulator VDD CE Pin No. 1 2, 5 3 4 6 Symbol VOUT GND CE NC VDD Description Output Pin of Voltage Regulator Ground Pin Chip Enable Pin No Connection Input Pin Vref 6 1 3 2,5 Current Limit VOUT GND IC323: SN74LV157APWR Quadruple 2-line to 1-line data selectors/multiplexers Pin numbers shown are for the D, DB, DGV, J, NS, PW, and W packages. 2 3 5 6 11 10 14 13 15 1 G A/B 4B 4A 3B 3A 2B 2A 1B 1A 4 7 9 12 1Y 2Y 3Y 4Y 1 2 3 4 5 6 7 8 16 15 14 13 12 11 10 9 A/B 1A 1B 1Y 2A 2B 2Y GND VCC G 4A 4B 4Y 3A 3B 3Y HDMI TRANSMITTER HDMI OUT YMC-500 to DIGITAL 4/8 to DIGITAL 5/8 to DIGITAL 5/8 to DIGITAL 1/8 to DIGITAL 3/8 to DIGITAL 1/8 to DIGITAL 7/8 to DIGITAL 5/8 to DIGITAL 4/8 YMC-700 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com ★ All voltages are measured with a 10MΩ/V DC electronic voltmeter. ★ Components having special characteristics are marked ⚠ and must be replaced with parts having specifications equal to those originally installed. ★ Schematic diagram is subject to change without notice. A 1 2 3 4 5 6 7 8 9 10 B C D E F G H I J K L M N 77 DIGITAL 3/8 YMC-700/YMC-500 IC331 IC334 IC334 IC334 IC334 IC334 IC333 IC332 POINT C XL331 (Pin 1 of IC334) C 0 0.5 0.2 0.4 0 0.4 0.3 0.3 0 3.3 0 3.3 0 0 0 0 3.1 0 0 3.3 3.3 1.3 3.3 3.3 0 0.4 0.3 3.1 1.4 0 0.2 0 0.2 0.2 1.9 0.2 0.2 0.3 1.8 3.3 0 0 0 1.3 0 1.8 1.6 1.6 1.8 3.3 0 3.3 0 1.6 1.3 0 0 0.2 0.2 0.2 0.2 0.2 0.2 3.3 3.3 0.2 0 1.3 0.2 0.2 3.1 0.2 0 0.3 0.3 0 1.6 0 0 0 0.5 0.6 0.7 3.3 0 0 3.3 3.0 0 0 0 0.7 0 1.9 1.4 1.9 0 0 0.8 0.8 0.7 3.3 1.3 3.3 3.3 0.2 0 0 0 0 0 3.3 0 0 1.7 3.3 0.4 0.2 0.3 3.2 0 0 0 0 0 0.4 0.3 0.3 0.4 1.3 3.3 3.0 0 0 0 0 0.4 1.3 3.3 1.3 0 0 0 0 0 2.5 0 0 3.3 3.3 0 3.1 0 0 0 3.3 3.3 0 0 0 1.3 0 0 0 0 1.3 0 0 1.3 1.3 3.3 1.3 1.3 1.3 0 2.5 2.5 2.5 0 1.3 3.3 3.3 0 3.3 0.2 0.2 0 0.2 0.2 3.3 0.2 0.2 0 3.3 3.3 0 3.0 1.9 1.4 1.9 0 0 0 0.8 0.8 0.7 0.7 3.3 0 0.2 0 0.2 0.2 3.3 3.1 0.2 0 0.2 0.3 3.3 0.3 0 0 1.6 3.3 0 0 0 0.5 0.6 0.7 0.7 0 0 1.3 0 0 0 0 0 0 0 0 0 0 3.3 0 0 0 0 1.8 1.8 1.8 0 0 1.7 0 3.3 0 3.3 3.3 3.3 1.3 0 3.3 0 0 0 0 0 0 0 3.3 0 3.3 3.3 0.7 0 0 0 0 3.3 0 VDD A3 A2 A1 A0 A10/AP A12 A13 CS RAS CAS WE LDQM VDD VSSQ DQ1 DQ2 DQ3 DQ4 DQ5 DQ6 DQ7 VDDQ VDDQ VSSQ DQ0 VDD VSS A4 A5 A6 A7 A8 A9 A11 NC CKE CLK UDQM NC VSS VDDQ DQ14 DQ13 DQ12 DQ11 DQ10 DQ9 DQ8 VSSQ VSSQ VDDQ DQ15 VSS 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 IC332: M12L64164A-5TG 1M x 16-bit x 4 banks synchronous DRAM CLK CS RAS CAS WE Command Decoder Control Logic Latch Circuit Input & Output Buffer Row Decoder Bank A Sense Amplifier Column Decoder Data Control Circuit L(U)DQM DQ CKE Address Clock Generator Row Address Buffer Column Address Buffer & & Refresh Counter Refresh Counter Mode Register Bank B Bank C Bank D VDD CE Pin No. 1 2, 5 3 4 6 Symbol VOUT GND CE NC VDD Description Output Pin of Voltage Regulator Ground Pin Chip Enable Pin No Connection Input Pin Vref 6 1 3 2,5 Current Limit VOUT GND IC333: R1172S121D-E2-F Voltage regulator IC334: 74LVC3GU04DP Triple inverter 1 1A 3Y 2 3 GND 4 2A 8 Vcc 7 6 1Y 5 3A 2Y No replacement part available. FPGA SDRAM YMC-500 to DIGITAL 5/8 to DIGITAL 4/8 to DIGITAL 6/8 to DIGITAL 1/8 to DIGITAL 1/8 to DIGITAL 3/8 to DIGITAL 5/8 to DIGITAL 5/8 to DIGITAL 5/8 to DIGITAL 5/8 to DIGITAL 5/8 to DIGITAL 4/8 to DIGITAL 4/8 to DIGITAL 4/8 to DIGITAL 2/8 to DIGITAL 2/8 to DIGITAL 2/8 to DIGITAL 5/8 YMC-700 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com ★ All voltages are measured with a 10MΩ/V DC electronic voltmeter. ★ Components having special characteristics are marked ⚠ and must be replaced with parts having specifications equal to those originally installed. ★ Schematic diagram is subject to change without notice. A 1 2 3 4 5 6 7 8 9 10 B C D E F G H I J K L M N YMC-700/YMC-500 78 DIGITAL 4/8 IC341 CB341 IC450 IC445 IC449 IC449 IC450 IC444 IC443 IC442 IC441 IC448 IC448 IC346 IC347 IC447 IC347 IC347 IC347 IC346 IC348 IC345 IC349 IC446 IC446 IC348 IC348 IC348 IC348 IC446 IC447 IC347 IC447 IC346 IC447 IC447 IC344 IC342 IC343 1.4 1.4 1.4 3.3 3.3 3.3 0 0 2.4 2.4 3.3 3.3 3.3 1.9 0 3.3 3.3 1.3 0 0 0 3.3 3.3 3.3 2.2 3.3 1.3 2.4 3.3 3.3 3.3 3.3 1.3 3.3 3.3 0 0 3.3 2.4 1.3 3.3 3.3 3.3 3.3 3.3 3.3 3.3 3.3 3.3 3.3 3.3 3.3 3.3 3.3 0 0.6 0 3.3 0 3.3 3.3 3.3 3.3 0 0 3.3 3.3 3.3 3.3 0 3.3 3.3 3.3 0 3.3 3.3 3.3 3.3 3.3 3.3 3.3 2.2 3.3 3.3 3.3 3.3 3.3 3.3 0.5 3.3 0 0.3 0.4 0 3.3 0.3 0.4 3.3 0 0.3 0.6 0 3.3 3.3 0 3.3 0.2 2.7 1.3 2.4 1.4 0 1.7 2.2 1.4 1.4 1.4 2.6 1.8 2.8 1.7 2.9 1.8 3.3 0 3.3 3.3 2.9 1.7 3.1 0 3.3 0.4 3.3 0 0.3 0.4 0 3.3 0.3 0.5 3.3 0 0.3 2.3 0 3.3 3.3 0 3.3 1.2 2.7 1.3 2.4 1.4 0 1.7 2.2 1.4 1.4 1.4 2.6 1.8 2.8 1.7 2.9 1.8 3.3 0 3.3 3.3 2.9 1.7 0.4 0 0 0 1.3 0 1.3 1.4 1.4 1.7 0 3.3 3.3 3.3 3.3 0 2.4 1.8 1.4 1.8 1.7 2.8 2.9 2.6 0 3.3 0 0 0.4 0.4 3.1 0.4 2.3 0.5 3.3 0.3 0.6 0.3 0.3 0.3 0.4 0.3 3.3 0 3.3 1.4 0.5 0.4 3.3 3.3 3.3 3.3 3.3 3.3 0 3.3 0 3.3 0 3.3 0 3.3 0 0.2 0 0 3.3 3.3 3.3 3.3 0 3.3 3.3 0 0 3.3 0 3.2 3.3 0 0.2 0 0 0 0 0 0.9 0 0 0 0 3.3 3.1 3.3 0 0 0 0 0 0 3.3 3.3 0 0 0 3.3 0 1.6 1.3 3.3 1.3 3.3 3.3 0 0 1.7 0 1.3 3.3 0 0 0 0 3.3 3.3 3.3 0 3.3 3.3 3.3 0 0 0 0 0 3.3 3.3 0.2 0 3.3 0.6 1.4 3.3 0 0.2 0.2 1.9 0.2 1.3 0.2 0.2 0.2 1.8 3.3 0 0 0 0 3.3 3.3 3.3 1.4 1.7 0 0 0 0 0 0 1.9 1.9 0 0 0 0 0 0 0 0 0 0 0 0 3.3 3.3 0 0.4 0.4 0.5 2.3 0.3 0.3 0.3 0.4 3.3 0 0 0 0 0 0 0 0 3.3 3.3 0 3.1 0.4 0.4 0.6 0.3 0.3 0.3 0.5 3.3 0 0 0 0 0 0 0 0 3.3 3.3 0 0 0 0 1.3 1.4 1.3 1.7 1.4 3.3 0 0 0 0 0 0 0 0 0 0 3.3 3.3 0 1.4 1.8 1.7 1.8 2.9 2.8 2.6 1.4 3.3 3.3 3.3 3.3 3.3 0 3.3 0 0.4 0.4 0.5 2.3 0.3 0.3 0.3 0.4 0 3.3 3.1 0.4 0.4 1.3 0.6 0.3 0.3 0.3 0.5 0 3.3 2.4 0 0 0 0 0 1.3 0 0 0 0 0 3.3 2.7 3.3 0 1.3 3.3 3.3 3.3 3.3 3.3 3.3 3.3 3.3 3.3 2.6 2.8 2.9 3.3 0 1.3 1.8 1.4 1.3 1.4 3.3 0 1.7 1.8 1.4 1.4 1.7 1.2 0 3.3 2.9 3.3 1.3 3.3 0.2 1.7 2.2 POINT D XL341 (Pin 10 of IC341) D 1 R4429 (+3.3EX) (13 pin) IC341 2 POWER ON POWER OFF 1 R4429 (+3.3EX) (13 pin) IC341 2 POWER OFF POINT E 1 / R4429 (+3.3EX), 2 / Pin 13 of IC341 E 1 2 POWER ON 1 R4429 (+3.3EX) (13 pin) IC341 2 IC341: AD91089ZSKBC Microprocessor PPI/GPIO L1 data memory JTAG test and emulation Voltage regulator L1 instruction memory Memory management unit Core/System bus interface Real time clock UART port IrDA® Serial port (2) DMA controller Boot ROM SPI port External port FLASH, SDRAM control Event controller/ Core timer Watch dock timer Timer0, Timer1, Timer2 IC445: LE25LA322M-TLM-E 32 k-bit serial SPI EEPROM SERIAL INTERFACE Y ·DECODER 1 2 3 4 VSS WP# SO CS# SI SCK HOLD# VDD 8 7 6 5 X · DECODER EEPROM Cell Array CONTROL LOGIC I/O BUFFERS and DATA LATCHES ADDRESS BUFFERS and LATCHES CS# SCK SI SO WP# HOLD# IC448-450: 74LVC1G08GW Single 2 input AND gate 1 B A 2 3 GND 5 4 Vcc Y IC349, 441-444: 74LVC245APW,118 Octal bus transceiver with direction pin with 5 V tolerant input/outputs (3-state) 1 DIR 2 A0 A1 A2 A3 A4 A5 A6 A7 3 4 5 6 7 20 Vcc 19 18 17 16 15 14 8 9 10 13 12 B6 B5 B4 B3 B2 B1 B0 OE 11 B7 GND IC342, 343: K4S560832J-UC75000 256 M synchronous DRAM Bank Select CLK Row Decoder I/O Control Output Buffer Sense AMP Address Register Data Input Register Column Decoder Latency & Burst Length Programming Register 16M x 4 / 8M x 8 / 4M x 16 16M x 4 / 8M x 8 / 4M x 16 16M x 4 / 8M x 8 / 4M x 16 16M x 4 / 8M x 8 / 4M x 16 Col. Buffer Row Buffer Refresh Counter ADD LCKE LRAS CLK LRAS LCAS Timing Register LCBR LWE LDQM DQi LDQM LWE LWCBR CKE CS LCBR WE L(U)DQM RAS CAS 1 VDD VSS VSS VSS N.C/RFU UDQM CLK CKE A12 A11 A9 A8 A7 A6 A5 A4 VSSQ VSSQ VDDQ VDDQ DQ15 DQ14 DQ13 DQ12 DQ11 DQ10 DQ9 DQ8 VDD VDDQ VDD VDDQ VSSQ VSSQ DQ0 DQ1 DQ2 DQ3 DQ4 DQ5 DQ6 DQ7 LDQM WE CAS RAS CS BA0 A0 A1 A2 A3 BA1 A10/AP 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 54 53 52 51 50 49 48 47 46 45 44 IC344: K8P6415UQB-PI4B000 64 Mb page mode NOR flash I/O Interface and Bank Control Bank 0 Cell Array Bank 0 Address Bank 3 Address Bank 1 Address Y Dec Latch and Control X Dec Vcc Vss CE OE WE RESET RY/BY WP/ACC A0-A21 DQ0-DQ15 1 A15 A14 A13 A12 A11 A10 A9 A8 A19 A20 A18 A17 A7 A6 A5 A4 A3 A2 A1 A21 WE RESET WP/ACC RY/BY A0 CE OE DQ0 DQ8 DQ1 DQ9 DQ2 DQ10 DQ3 DQ11 Vcc DQ4 DQ12 DQ5 DQ13 DQ6 DQ14 DQ7 DQ15 Vss N.C A16 Vss 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 28 29 30 25 26 27 31 32 33 34 35 36 37 38 39 40 41 42 43 48 47 46 45 44 Bank 3 Cell Array Bank 1 Cell Array Y Dec Y Dec X Dec Block Inform Erase Control X Dec Latch and Control Latch and Control High Voltage Gen. Program Control IC348, 446: 74LVC32APW Quad 2 input OR gate 1 1A 2 1B 3 1Y 4 2A 5 2B 6 2Y 7 14 Vcc 13 4B 12 4A 11 4Y 10 3B 9 3A 8 3Y GND IC447: 74LVC00APW Quad 2 input NAND gate 1 1A 2 1B 3 1Y 4 2A 5 2B 6 2Y 7 14 Vcc 13 4B 12 4A 11 4Y 10 3B 9 3A 8 3Y GND IC347: 74LVC14APW Hex inverter schmitt trigger with 5 V tolerant input 1 1A 1Y 2 3 2Y 4 2A 3A 5 6 3Y 7 14 Vcc 13 12 6A 11 6Y 10 9 4A 8 4Y 5A 5Y GND IC345: SN74LV123APWR Dual retriggerable monostable multivibrators with schmitt-trigger inputs 1B 1CLR 2CLR 1A A B Q Q CLR 2B 2A VCC 1Q 2Q GND 1Q 2Q 2Cext 2Rext/Cext Rext/Cext Cext 1Rext/Cext 1Cext 2 3 4 5 6 7 8 1 15 14 13 12 11 10 9 16 R IC346: 74LVC08APW Quad 2 input AND gate 1 1A 2 1B 3 1Y 4 2A 5 2B 6 2Y 7 14 Vcc 13 4B 12 4A 11 4Y 10 3B 9 3A 8 3Y GND MICROPROCESSOR EEPROM SDRAM BUS BUFFER SDRAM FLASH MEMORY No replacement part available. YMC-500 to DIGITAL 5/8 to DIGITAL 8/8 to DIGITAL 8/8 to DIGITAL 3/8 to DIGITAL 8/8 to DIGITAL 8/8 to DIGITAL 3/8 to DIGITAL 8/8 to DIGITAL 8/8 to DIGITAL 3/8 to DIGITAL 3/8 to DIGITAL 6/8 to DIGITAL 6/8 to DIGITAL 6/8 to DIGITAL 6/8 to DIGITAL 5/8, 6/8 to DIGITAL 6/8, 7/8 to DIGITAL 5/8 YMC-700 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com ★ All voltages are measured with a 10MΩ/V DC electronic voltmeter. ★ Components having special characteristics are marked ⚠ and must be replaced with parts having specifications equal to those originally installed. ★ Schematic diagram is subject to change without notice. A 1 2 3 4 5 6 7 8 9 10 B C D E F G H I J K L M N 79 DIGITAL 5/8 YMC-700/YMC-500 IC351 IC352 IC356 IC354 IC353 3.3 0 5.1 0 0 0 0 0 0 3.3 0 3.3 3.3 0 0 0 0 0 3.3 0 0 0 0 0 3.3 0 3.3 3.3 3.3 5.1 0 3.3 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 3.3 3.3 0 3.3 3.3 3.3 0 3.3 0 0 0 0 0 3.3 0 0 0 3.3 1.8 0 3.3 0 0 3.3 0 0 3.3 5.1 3.3 0 0 3.3 0 3.3 0 3.3 0 0 3.3 0 3.3 3.3 3.3 0 3.3 0 3.3 0 3.3 3.3 3.3 3.3 3.3 3.3 3.3 3.3 3.3 3.3 3.3 3.3 0 0 3.3 0 0 3.3 1.7 3.3 3.3 0 3.0 3.3 3.3 3.3 3.3 0 3.3 3.3 3.3 0 3.3 3.3 3.3 5.1 0 3.3 3.3 0 3.3 0 3.2 3.3 3.3 3.3 0 0 0 0 0 3.3 0 5.1 3.3 3.3 3.3 3.3 3.3 3.3 0 3.3 0 3.3 0 0 0 0 5.1 0 0 0 0 0 0 0 0 0 0 0 0 5.1 0 0 4.9 5.1 5.1 5.1 5.1 3.3 0 0 0 0 0 0 0 0 0 0 0 3.3 3.3 3.3 3.3 3.3 0 3.3 0 3.3 0 0 5.0 3.3 3.3 3.3 4.0 0 IC352: SN74AHCT245PWR Octal bus transceivers with 3-state outputs 1 2 3 4 5 6 7 8 9 10 20 19 18 17 16 15 14 13 12 11 DIR A1 A2 A3 A4 A5 A6 A7 A8 GND VCC OE B1 B2 B3 B4 B5 B6 B7 B8 DIR OE A1 B1 To Seven Other Channels 1 2 19 18 IC353, 356: 74LVC574APW Octal D type flip flop with 5 V tolerant inputs/outputs positive edge trigger 3-state 1 OE 2 D0 D1 D2 D3 D4 D5 D6 D7 3 4 5 6 7 20 Vcc 19 18 17 16 15 14 8 9 10 13 12 Q7 Q6 Q5 Q4 Q3 Q2 Q1 Q0 11 CP GND 1 2 3 4 5 6 7 8 9 10 20 19 18 17 16 15 14 13 12 11 OE 1D 2D 3D 4D 5D 6D 7D 8D GND VCC 1Q 2Q 3Q 4Q 5Q 6Q 7Q 8Q CLK IC354: SN74AHCT574PWR Octal edge-triggered D-type flip-flops with 3-state outputs OE 1 11 2 19 CLK 1D C1 1D 1Q 9 12 8D C8 8D 8Q No replacement part available. NPGA to DIGITAL 8/8 to DIGITAL 6/8 to DIGITAL 3/8 to DIGITAL 7/8 to DIGITAL 6/8 to DIGITAL 1/8 to DIGITAL 2/8 to DIGITAL 6/8 to DIGITAL 3/8 to DIGITAL 8/8 to DIGITAL 7/8 YMC-500 to DIGITAL 8/8 to DIGITAL 8/8 to DIGITAL 8/8 to DIGITAL 1/8 to DIGITAL 7/8 to DIGITAL 8/8 to DIGITAL 8/8 to DIGITAL 8/8 to DIGITAL 4/8 to DIGITAL 6/8 to DIGITAL 3/8, 8/8 to DIGITAL 8/8 to DIGITAL 3/8 to DIGITAL 3/8 to DIGITAL 5/8 to DIGITAL 5/8 to DIGITAL 1/8 to DIGITAL 2/8 to DIGITAL 5/8 to DIGITAL 8/8 to DIGITAL 8/8 to DIGITAL 7/8 to DIGITAL 5/8 to DIGITAL 3/8 to DIGITAL 7/8 to DIGITAL 7/8 to DIGITAL 7/8 to DIGITAL 7/8 to DIGITAL 7/8 to DIGITAL 8/8 to DIGITAL 8/8 to DIGITAL 6/8 to DIGITAL 8/8 to DIGITAL 1/8 to DIGITAL 1/8 to DIGITAL 1/8 to DIGITAL 2/8 to DIGITAL 2/8 to DIGITAL 6/8 to DIGITAL 6/8 to DIGITAL 3/8 to DIGITAL 8/8 to DIGITAL 8/8 YMC-700 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com ★ All voltages are measured with a 10MΩ/V DC electronic voltmeter. ★ Components having special characteristics are marked ⚠ and must be replaced with parts having specifications equal to those originally installed. ★ Schematic diagram is subject to change without notice. A 1 2 3 4 5 6 7 8 9 10 B C D E F G H I J K L M N YMC-700/YMC-500 80 DIGITAL 6/8 IC361 CB361 CB362 IC366 IC362 CB363 IC365 IC363 IC367 IC367 0 0 0 0 0 0 0 0 0 0 0 0 3.3 3.3 3.3 0 3.3 0 0 0 5.1 3.3 0 5.1 3.3 3.3 3.3 0 0 0 0 0 6.2 5.1 5.1 0 4.3 0 0 5.1 5.1 0 5.1 0 0 0 0 5.1 0 6.2 6.2 0 0 0 0 0 0 3.3 0 3.3 3.3 3.3 0 0 0 3.3 3.3 3.3 3.3 0 3.3 3.3 3.3 3.3 3.3 3.3 3.3 1.7 3.3 3.3 0 3.3 3.3 3.3 0 0 3.3 3.3 3.3 0 0 0 1.9 0 0 3.3 3.3 3.3 3.3 4.3 0 0 3.3 0 0 0 0 0 0 0 3.3 3.3 3.3 3.3 3.3 0 0 0 1.9 0 0 3.3 0 0 0 3.3 0 0 0 0 0 0 0 0 0 0 3.3 0 0 0 0 0 0 0 0 0 0 3.3 0 0 3.3 0 3.3 3.3 3.3 3.3 3.3 3.3 0 3.3 3.3 3.3 3.3 3.3 3.3 3.3 0 3.3 3.3 1.9 0 0 5.1 3.3 3.3 3.3 3.3 1.0 0.9 0 0 1.3 0 0 0 0 0 0 1.3 0 0 3.3 0 1.3 0 0 3.3 0 0 0 0 0 0 3.3 0 0 0 0 0 3.3 0 0 0 3.3 0 1.9 0 0 3.3 0 3.1 3.3 3.3 3.3 0 3.3 3.3 0 0 1.3 0 3.3 3.3 3.3 3.3 3.3 3.3 0 2.1 0 0 3.3 0 3.3 0 3.3 0 0 0 0 0 0 0 0 0 0 1.9 3.3 3.3 0 0 0 0 3.3 0 1.9 0 1.3 1.7 0 0 0 0 3.3 0 0 3.3 0 0 0 3.3 0 3.3 POINT F XL361 (Pin 38 of IC366) POINT G XL362 (Pin 11 of IC361) F G IC366: TE4300PF SD memory card, SDIO card, Multimedia card controller VSHOST #RST #RD #RD #WR #INT CLK OCTL MCLK MWP XMCD CMD DAT(3:0) DT(15:0) BA(4:0) #CS1 CS2 VSCMDT VRAMCNT Response,COMMAND,Argument RCLK VTIMER VCKCNT X1 X0 VSMDIF RAM256B Dual Port RAM TMCK CLKP IC361: ISP1760BE Embedded hi-speed USB host controller ISP1760BE 37 to 39, 41 to 43, 45 to 47, 49, 51, 52, 54, 56 to 58, 60 to 62, 64 to 66, 68 to 70, 72 to 74, 76 to 78, 80 82, 84, 86, 87, 89, 91, to 93, 95 to 98, 100 to 103, 105 SUSPEND/ WAKEUP_N BAT_ON_N REG1V8 REG3V3 REF5V GND(OSC) GNDA GNDC GNDD GNDA VCC(5V0) RESET_N CLKIN XTAL1 XTAL2 VCC(I/O) 119 122 17 106 107 108 112 114 116 11 12 10, 40, 48, 59, 67, 75, 83, 94, 104, 115 16-bit or 32-bit 13 30 MHz 60 MHz 110 5, 50, 85, 118 4, 17, 24 31, 123 53, 88, 121 14, 36, 44, 55, 63, 71, 79, 90, 99, 109 004aaa435 6, 7 9 2 8 16 15 20 19 18 21 127 23 22 27 26 25 28 128 30 29 34 33 32 35 1 GLOBAL CONTROL AND POWER MANAGEMENT HC PAYLOAD MEMORY (60 kB) HC PTD MEMORY (3 kB) RISC PROCESSOR INTERFAC: A[17:1] DATA [15:0]/DATA [31:0] GENERIC PROCESSOR BUS MEMORY MANAGEMENT UNIT + INTERRUPT CONTROL + SLAVE DMA CONTROLLER + HARDWARE CONFIGURATION REGISTERS 5 V-TO-1.8 V VOLTAGE REGULATOR 5 V-TO-3.3 V VOLTAGE REGULATOR HI-SPEED USB ATX3 DIGITAL AND ANALOG OVERCURRENT DETECTION PIE USB HIGH-SPEED DATA PATH EHCI AND OPERATIONAL REGISTERS TRANSACTION TRANSLATOR AND RAM MEMORY ARBITER AND FIFO PLL POWER-ON RESET AND VBAT ON OC3_N PSW3_N DP3 GND (RREF3) RREF3 DM3 USB FULL-SPEED AND LOW-SPEED DATA PATH PORT ROUTING CONTROL LOGIC + HOST AND HUB PORT STATUS PSW2_N OC2_N PSW1_N OC1_N GNDA HI-SPEED USB ATX2 DP2 GND (RREF2) RREF2 DM2 GNDA HI-SPEED USB ATX1 DP1 GND (RREF1) RREF1 DM1 DACK IRQ WR_N RD_N CS_N DWEQ IC362: LAN9217-MT Digital ic System Memory System Memory System Peripherals External PHY Magnetics Magnetics LEDS/ GPIO EEPROM (Optional) Embedded Microprocessor/ Microcontroller Optional MII 25MHz XTAL Optional Ethernet LAN9217 IC365: NJM2386DL3-05 (TE1) Low dropout voltage regulator with ON/OFF control ON/OFF control Over Voltage Protection Bandgap Reference VIN Cont GND VOUT Over Current Protection Thermal Protection VIN 4 EN 1 2 5 GATE CONTROL UVLO THERMAL SHUTDOWN CURRENT LIMIT FLAG DELAY VOUT 3 FLG GND IC363: R5523N001A-TR-F High side switch IC ETHERNET USB HOST SDIO I/F No replacement part available. to DIGITAL 5/8 to DIGITAL 5/8 to DIGITAL 5/8 to DIGITAL 5/8 to DIGITAL 6/8 to DIGITAL 4/8 to DIGITAL 4/8 to DIGITAL 4/8 YMC-500 to DIGITAL 5/8 YMC-700 YMC-700 to WIFI_CB601 (YMC-700) Page 89 J6 To USB To NETWORK w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com ★ All voltages are measured with a 10MΩ/V DC electronic voltmeter. ★ Components having special characteristics are marked ⚠ and must be replaced with parts having specifications equal to those originally installed. ★ Schematic diagram is subject to change without notice. A 1 2 3 4 5 6 7 8 9 10 B C D E F G H I J K L M N 81 DIGITAL 7/8 YMC-700/YMC-500 IC371 CB371 IC375 IC374 IC377 IC471 IC373 IC372 IC474 IC474 IC478 IC478 IC478 IC378 IC378 IC379 IC479 IC479 IC379 IC379 IC473 IC472 IC379 IC379 IC379 IC379 IC478 IC376 POINT H XL371 (Pin 29 of IC374) H 0 5.1 5.1 5.1 5.1 5.1 0 0 0 0 2.4 0 0 0 0 0 0 3.3 0 1.7 0 0 3.3 1.7 3.3 1.3 1.3 0 2.5 0.6 3.3 0 0 3.3 0 0 3.3 3.3 3.3 0 0 0 0 3.3 0 1.7 1.6 0 1.7 1.3 0 1.6 1.7 1.6 1.7 0 1.7 3.3 3.3 0 0 0 3.3 1.6 1.6 1.6 3.3 1.7 3.3 1.7 1.6 3.3 0 0 0.9 0 1.3 1.3 0 0 0 0 1.7 1.6 1.7 1.7 0 3.3 0 0 1.7 1.7 1.7 1.7 0 3.3 1.7 1.7 3.3 1.3 1.7 3.3 1.3 2.5 2.5 0 2.5 0 3.3 0 0 0 0.4 0.3 1.1 1.1 0 0 0 1.7 1.9 1.5 2.4 0.8 0.8 0.8 3.3 3.3 3.3 0 0 0 0 1.3 0 3.3 0 0 0 0 1.3 1.6 0 3.3 1.3 0 0 0 1.3 0 3.3 3.3 0 3.3 1.3 3.3 0 3.3 3.3 3.3 3.3 1.7 3.3 0 3.3 0 0.7 0.5 0 0.5 0.6 0.5 0.8 0.5 3.3 0.8 0.5 0.5 0.5 1.5 0.5 1.2 3.3 0 3.3 3.3 1.2 3.3 3.3 1.2 0.5 0 0.5 0.5 3.3 0.5 0.5 0 0.5 2.8 3.3 3.3 3.2 3.3 1.9 3.3 3.3 0.4 0.8 0.8 0.8 2.4 3.3 0 0.7 0 0 0.6 3.3 0.8 0.8 0 0.4 0.5 3.3 0.5 0 0.4 1.7 3.3 0 0.3 1.1 1.1 1.7 1.9 1.5 0 0 3.3 3.3 3.3 1.3 3.3 0 3.3 1.9 3.3 3.3 0.4 3.3 0.8 1.3 0.8 0.5 0 2.4 1.3 1.5 1.9 3.3 1.7 1.1 0 1.1 0 3.3 0.3 1.3 0 0 3.3 1.7 1.7 1.7 0 1.7 0 0.7 3.3 0 0.7 0 3.3 0 0 0 1.3 1.3 0 1.3 3.3 0 1.8 0 0 3.3 1.3 0.7 1.3 0 3.3 0 0 0 0 0 3.2 2.8 0 0.5 0.5 3.3 1.3 0 0.7 3.3 1.7 0.5 0.5 0 0.5 0.5 1.5 1.2 1.3 0 1.3 0.6 0.8 3.3 0 0.8 0.5 1.3 0.5 0.4 0 3.3 0 0.4 3.3 3.3 2.5 5.1 0 0 0 1.7 1.7 1.7 3.3 3.3 3.3 0 2.1 4.9 0 0 0 1.9 0 0 0.9 1.0 0 1.7 4.9 5.1 0 0 1.1 5.1 3.3 3.3 3.3 1.7 1.9 3.3 3.3 1.7 1.7 1.7 1.7 1.7 1.7 0 0 3.3 3.3 0 3.3 3.3 3.3 3.3 0 3.3 3.3 3.3 3.3 3.3 0 3.3 0 0 0 0 0 0 3.3 3.3 1.3 1.3 0.7 0 0 0 1.7 1.9 1.7 1.7 1.7 3.3 0 1.7 1.6 3.3 3.0 0 0 3.3 3.3 2.9 0 0 5.1 2.9 0.6 ANALOG IN C/SW FL/FR SL/SR DIGITAL IN VDD A3 A2 A1 A0 A10/AP A12 A13 CS RAS CAS WE LDQM VDD VSSQ DQ1 DQ2 DQ3 DQ4 DQ5 DQ6 DQ7 VDDQ VDDQ VSSQ DQ0 VDD VSS A4 A5 A6 A7 A8 A9 A11 NC CKE CLK UDQM NC VSS VDDQ DQ14 DQ13 DQ12 DQ11 DQ10 DQ9 DQ8 VSSQ VSSQ VDDQ DQ15 VSS 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 IC372: M12L64164A-5TG 1M x 16-bit x 4 banks synchronous DRAM CLK CS RAS CAS WE Command Decoder Control Logic Latch Circuit Input & Output Buffer Row Decoder Bank A Sense Amplifier Column Decoder Data Control Circuit L(U)DQM DQ CKE Address Clock Generator Row Address Buffer Column Address Buffer & & Refresh Counter Refresh Counter Mode Register Bank B Bank C Bank D IC371: D70YE101BRFP266 Floating-point digital signal processors 256 256 C67x+ Microprocessor D1 64 R/W Data D2 R/W Program Fetch Memory Controller Program/Data RAM 256K Bytes JTAG EMU McASP DMA Bus Peripheral Configuration Bus McASP0 16 Serializes McASP1 6 Serializes McASP2 2 Serializes DIT Only SPI1 SPI0 I2C0 I2C1 RTI PLL Program/Data ROM Page1 256K Bytes Program/Data ROM Page2 256K Bytes Program/Data ROM Page3 256K Bytes High-performance Crossbar Switch CSP PMP DMP Program Cache 32K Bytes I/O I/O MAX0 MAX1 Events In CONTROL dMAX EMIF Peripheral Interrupt and DMA Events Interrupts Out INT Data 256 256 256 256 32 32 32 32 32 32 32 32 32 32 32 64 32 32 32 32 32 32 32 32 32 32 IC376: TAS5086DBT PWM processor DVDD Power Supply Serial Data Interface Channel Selector Block Down- mix Clock Rate /Error Detection and PLL Serial Control Interface System Control MUX MUX MUX 6 DVSS DVSS_ESD VR_DIG VR_ANA VR_OSC AVDD AVSS_PLL VREG_EN SDIN1 SDIN2 SDIN3 SDIN4 MCLK SCLK LRCLK PLLFLTP PLLFLTM HFCLK OSCFLT OSC_RES SDA SCL RESET PDN MUTE BKNDERR SDIN4 1-5 1-5 1-6 L’ L’ 1LF MUX MUX PWM Control Channel Six Processing Bass Management R’ 2RF 5C (L’+R’)/2 MUX I2S Serial Output Downmix SDIN4 (L’+R’)/2 3LS Ch 1-6 Vol PWM 4RS R’ 1-6 Chan. PWM1 MUX 6 PWM2 MUX 6 PWM3 MUX 6 PWM4 MUX 6 PWM5 MUX 6 PWM6 VALID1 VALID2 SDOUT VR_ANA 1 AVDD 2 AVSS 3 AVSS 4 PLL_FLTM 5 PLL_FLTP 6 AVSS 7 MCLK 8 RESET 9 PDN 10 DVDD 11 DVSS 12 DVSS_OSC 13 OSC_RES 14 VR_OSC 15 MUTE 16 SDA 17 SCL LRCLK PWM_1 PWM_2 PWM_3 PWM_4 PWM_5 PWM_6 VALID2 VALID1 VR_DIG DVSS DVSS BKND_ERR SDIN1 SDIN2 SDIN3 SDIN4 SDOUT RESERVED SCLK 18 19 38 37 36 35 34 33 32 31 30 29 28 27 26 25 24 23 22 21 20 IC379: SN74LVU04APWR Hex inverters GND Y3 A3 A2 A1 VCC A6 A5 A4 Y6 Y5 Y4 Y2 Y1 1 2 3 4 5 6 7 14 13 12 11 10 9 8 IC373: K8P6415UQB-PI4B000 64 Mb page mode NOR flash I/O Interface and Bank Control Bank 0 Cell Array Bank 0 Address Bank 3 Address Bank 1 Address Y Dec Latch and Control X Dec Vcc Vss CE OE WE RESET RY/BY WP/ACC A0-A21 DQ0-DQ15 1 A15 A14 A13 A12 A11 A10 A9 A8 A19 A20 A18 A17 A7 A6 A5 A4 A3 A2 A1 A21 WE RESET WP/ACC RY/BY A0 CE OE DQ0 DQ8 DQ1 DQ9 DQ2 DQ10 DQ3 DQ11 Vcc DQ4 DQ12 DQ5 DQ13 DQ6 DQ14 DQ7 DQ15 Vss N.C A16 Vss 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 28 29 30 25 26 27 31 32 33 34 35 36 37 38 39 40 41 42 43 48 47 46 45 44 Bank 3 Cell Array Bank 1 Cell Array Y Dec Y Dec X Dec Block Inform Erase Control X Dec Latch and Control Latch and Control High Voltage Gen. Program Control VDD CE Pin No. 1 2, 5 3 4 6 Symbol VOUT GND CE NC VDD Description Output Pin of Voltage Regulator Ground Pin Chip Enable Pin No Connection Input Pin Vref 6 1 3 2,5 Current Limit VOUT GND IC471: R1172S121D-E2-F Voltage regulator IC472, 473: TC74VHC153FT Dual 4-channel multiplexer 14 A S0 S0 6 1C0 2 B S1 S1 S2 S2 S3 S3 S0 7 1Y 5 1C1 S1 4 1C2 S2 1 1G 3 1C3 S3 10 2C0 S0 9 2Y 11 2C1 S1 12 2C2 S2 15 2G 13 2C3 S3 IC478: 74LVC3G04DP Triple inverter 1 1A 3Y 2 3 GND 4 2A 8 Vcc 7 6 1Y 5 3A 2Y 1 2 3 4 5 6 7 8 9 10 20 19 18 17 16 15 14 13 12 11 VINL VINR VREF1 VREF2 VCC AGND PDWN BYPAS TEST LRCK MODE1 MODE0 FMT1 FMT0 OSR SCKI VDD DGND DOUT BCK IC375: PCM1803DBR Stereo A/D converter BCK VINL Reference VREF1 VREF2 VINR Delta-Sigma Modulator Delta-Sigma Modulator x 1/64, x 1/128 Decimation Filter With High-Pass Filter Power Supply AGND VCC VDD DGND Clock and Timing Control Serial Interface Mode/ Format Control LRCK DOUT FMT0 FMT1 MODE0 MODE1 BYPAS OSR PDWN SCKI TEST Microcontroller I/F Cbit, Pc Fs calculator IC374: LC89058WD-E Digital audio interface receiver 1 13 48 2 47 28 27 46 45 44 32 34 40 CL CE DI DO RERR SDIN RDATA RMCK RBCK RLRCK SBCK SLRCK XMODE AUDIO INT CKST MOUT GPIO0 GPIO1 GPIO2 GPIO3 RXOUT2 RXOUT1 RX0 RX1 RX2 RX3 RX4 RX5 RX6 LPF XIN XOUT XMCK 41 39 38 37 36 24 21 4 8 10 29 9 5 3 16 22 17 20 23 35 33 Input Selector PLL Oscillation Amplifier Clock Selector Clock Divider Demodulation & Lock detect Data Selector IC378, 474: 74LVC08APW Quad 2 input AND gate 1 1A 2 1B 3 1Y 4 2A 5 2B 6 2Y 7 14 Vcc 13 4B 12 4A 11 4Y 10 3B 9 3A 8 3Y GND No replacement part available. DSP SDRAM FLASH MEMORY YMC-500 to DIGITAL 5/8 to DIGITAL 4/8 to DIGITAL 4/8 to DIGITAL 4/8 to DIGITAL 2/8 to DIGITAL 1/8 to DIGITAL 5/8 to DIGITAL 5/8 to DIGITAL 2/8 to DIGITAL 1/8 to DIGITAL 8/8 to DIGITAL 8/8 to DIGITAL 8/8 to DIGITAL 8/8 to DIGITAL 5/8 to DIGITAL 5/8 to DIGITAL 5/8 to DIGITAL 5/8 AD CONVERTER PWM MODULATOR DIR YMC-700 AUDIO IN w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com ★ All voltages are measured with a 10MΩ/V DC electronic voltmeter. ★ Components having special characteristics are marked ⚠ and must be replaced with parts having specifications equal to those originally installed. ★ Schematic diagram is subject to change without notice. A 1 2 3 4 5 6 7 8 9 10 B C D E F G H I J K L M N YMC-700/YMC-500 82 DIGITAL 8/8 JK381 IC382 IC381 IC386 IC386 IC386 IC386 IC386 IC384 CB381 CB385 CB384 IC383 CB385 CB383 CB382 JK381 JK382 JK382 3.4 3.2 3.3 0 3.3 2.3 2.3 0 0.4 3.3 1.2 0.4 0 0 0 2.3 3.3 0 4.0 3.3 3.3 0.6 0 0.7 3.3 3.3 5.1 3.3 3.3 3.3 3.3 0 3.3 3.3 3.3 0 3.3 3.3 3.3 3.3 3.3 2.3 2.3 1.7 0 1.7 1.7 0 1.7 0 0 0 1.7 0 1.7 1.7 3.3 3.3 0 0 0 3.3 5.0 1.7 0 1.7 1.7 0 3.3 1.7 1.7 1.7 1.7 1.7 1.7 1.7 1.7 0 3.3 1.7 1.7 1.7 0 0 0 0 0 0 0 0 0 3.3 3.3 3.3 3.3 3.3 0 1.0 0 3.3 3.3 0 3.3 3.3 0 0 3.3 3.3 3.3 3.3 3.3 3.2 3.3 0 3.3 3.3 0 0.9 6.2 3.3 0 6.2 0 0.9 6.2 6.0 6.2 6.2 0 0 0 0 6.2 6.2 6.0 6.2 6.2 0 6.2 6.2 6.2 5.1 0 6.0 6.2 6.2 0 6.2 3.3 3.3 0 3.3 0 0 5.1 5.1 3.3 0 5.1 5.1 0 3.3 0 3.3 0 0 0 0 2.5 2.5 0 0 0 0 0 5.1 0 5.1 0 0 3.3 2.6 0 2.6 3.3 5.1 6.2 3.3 1.9 0 3.3 3.3 6.2 5.1 0 3.0 3.3 3.3 1.9 3.3 3.3 0 3.3 0 3.3 3.3 3.3 3.4 0.4 0.4 CENTER SURROUND L SUB WOOFER FRONT L ANALOG IN POINT J XL381 (Pin 7 of IC383) J IC386: 74LVC125APW Quad buffer/line driver with 5 V tolerant input/outputs 3-state 1 1A 2 1OE 2OE 3 1Y 4 2A 5 6 2Y 7 14 Vcc 13 4OE 12 4A 11 4Y 10 3OE 9 3A 8 3Y GND IC385: 74LVC245APW,118 Octal bus transceiver with direction pin with 5 V tolerant input/outputs (3-state) 1 DIR 2 A0 A1 A2 A3 A4 A5 A6 A7 3 4 5 6 7 20 Vcc 19 18 17 16 15 14 8 9 10 13 12 B6 B5 B4 B3 B2 B1 B0 OE 11 B7 GND IN1 IN2 IN3 MUX T/H VA 8-Bit SUCCESSIVE APPROXIMATION ADC GND IN4 GND SCLK CONTROL LOGIC CS DIN DOUT CS 1 VA 2 GND 3 IN4 4 IN3 5 SCLK ADC084S021 10 DOUT 9 DIN 8 IN1 7 IN2 6 IC381: ADC084S021 CIMM 4-channel, 200 kSPS, 8-bit A/D converter IC384: NJM2386DL3-05 (TE1) Low dropout voltage regulator with ON/OFF control ON/OFF control Over Voltage Protection Bandgap Reference VIN Cont GND VOUT Over Current Protection Thermal Protection IC382: SN74LV4051APWR 8-channel analog multiplexers/demultiplexers Y0 Y1 Y2 Y3 Y4 Y5 Y6 Y7 COM INH C B A 11 10 9 6 3 13 14 15 12 1 5 2 4 1 2 3 4 5 6 7 8 9 10 16 15 14 13 12 11 Y4 Y6 COM Y7 Y5 INH GND GND VCC Y2 Y1 Y0 Y3 A B C INPUTS ON CHANNEL INH L L L L L L L L H L L L H H H H X C L L H H L L H H X L H L H L H L H X L Y1 Y2 Y3 Y4 Y5 Y6 Y7 None Y0 B A IR BLASTER AD CONVERTER SELECTOR1 YMC-500 to DIGITAL 1/8 to DIGITAL 5/8 to DIGITAL 5/8 to DIGITAL 5/8 to DIGITAL 7/8 to DIGITAL 4/8 to DIGITAL 4/8 to DIGITAL 5/8 to DIGITAL 5/8 to DIGITAL 5/8 to DIGITAL 5/8 to DIGITAL 5/8 to DIGITAL 5/8 to DIGITAL 7/8 to DIGITAL 4/8 to DIGITAL 4/8 to DIGITAL 4/8 to DIGITAL 4/8 REMOTE CONTROL OUT1/2 OUT3/IN to DIGITAL 5/8 to DIGITAL 7/8 to DIGITAL 7/8 to DIGITAL 4/8 to DIGITAL 5/8 YMC-700 to OPERATION (2)_CB154 Page 83 B4 to MAIN_W2001 Page 87 L7 to MAIN_W1 Page 84 N6 to MAIN_CB101 Page 86 E9 to MAIN_CB50 Page 85 B6 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com ★ All voltages are measured with a 10MΩ/V DC electronic voltmeter. ★ Components having special characteristics are marked ⚠ and must be replaced with parts having specifications equal to those originally installed. ★ Schematic diagram is subject to change without notice. A 1 2 3 4 5 6 7 8 9 10 B C D E F G H I J K L M N 83 OPERATION YMC-700/YMC-500 CB151 CB154 CB153 W1851 W1603B CB171 IC171 IC171 CB172 JK151 IC151 IC151 CB152 W1603A W1601B W1601A W1602 IC161 IC161 5.0 0 0 0 0 5.0 -5.1 0 0 0 0 0 1.6 0 3.3 3.3 0 0.6 0.7 3.3 3.3 1.6 3.3 0.7 2.2 2.2 5.1 2.1 5.1 0 3.3 3.3 0 3.3 3.3 3.3 0.6 0.7 3.3 0 3.3 3.1 1.6 3.3 3.1 0 0 3.1 3.3 3.1 3.1 3.1 1.6 1.5 1.6 1.6 3.1 0 0 0 0 0 0.7 0.6 0 3.3 0 3.3 1.4 0 0.7 0 3.1 0 3.1 1.6 3.3 1.6 1.6 1.6 0 1.4 1.4 0.7 0.7 0 3.3 3.3 3.3 3.3 3.3 3.3 0.7 0.6 0 3.3 5.1 3.3 3.3 3.3 0 0 4.5 0 0 3.3 3.3 3.3 0 0 0 -5.1 3.3 4.0 3.3 3.3 3.3 3.3 3.3 3.3 3.3 3.3 0.6 0 3.3 3.3 5.1 0 0 3.3 3.3 3.3 5.1 0 0.6 0.7 3.3 3.3 3.3 3.3 3.3 3.3 0.7 IC161, 171: BA4510F-E2 Dual operational amplifier IC151: NJM4565M (TE1) Dual operational amplifier 8 2, 6 3, 5 1, 7 4 V+ –INPUT +INPUT V– OUTPUT – + – + 1 2 3 4 8 7 6 5 OUT 1 -IN1 +IN1 VEE VCC OUT 2 -IN2 +IN2 YPAO MIC VOLUME CONTROL BACK ENTER STANDBY/ ON OPERATION (2) OPERATION (1) OPERATION (6) OPERATION (4) OPERATION (3) OPERATION (5) YMC-500 YMC-700 Ohm 0 +2.2k +4.7k +8.2k +27.0k V 0 – 0.05 0.52 – 0.67 1.27 – 1.42 1.92 – 2.07 2.60 – 2.76 A/D value (3.3 V=255) 0 – 4 40 – 52 98 – 110 148 – 160 201 – 213 KEY1 (7 pin of IC381) 〈 (LEFT) 〈 (UP) 〉 (RIGHT) 〉 (DOWN) ENTER Ohm 0 +10.0k V 0 – 0.05 1.57 – 1.72 A/D value (3.3 V=255) 0 – 4 121 – 133 KEY2 (6 pin of IC381) CONTROL BACK KEY1 KEY2 Destination detection for A/D port Pull-up resistance 10 k-ohms to DIGITAL_CB383 Page 82 D9 to MAIN_W1000 Page 86 D2 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com ★ All voltages are measured with a 10MΩ/V DC electronic voltmeter. ★ Components having special characteristics are marked ⚠ and must be replaced with parts having specifications equal to those originally installed. ★ Schematic diagram is subject to change without notice. A 1 2 3 4 5 6 7 8 9 10 B C D E F G H I J K L M N YMC-700/YMC-500 84 MAIN 1/5 CB1 CB2 IC2 IC1 IC3 IC14 IC15 IC8 IC7 IC13 IC12 IC6 IC10 IC4 IC11 W1 IC5 (0) (15.4) (2.6) (1.3) (0) (0) (1.3) (15.4) (0) (0) (1.7) (2.2) (4.0) (1.6) (0) (59.5) (233.2) (163.4) (163.4) (233.2) (163.3) (59.8) (163.7) 4.0 8.1 4.0 0 0 0 0 0 28.0 18.0 18.0 12.0 5.1 5.1 0 0 -5.0 5.1 5.1 0 -5.0 12.0 18.0 18.0 18.0 18.0 -18.3 -18.3 13.2 13.2 0 0 0 13.2 0 13.2 12.9 -0.2 8.7 4.2 0 8.7 0 8.7 8.2 4.8 9.5 3.3 0 3.3 0 0.8 0.9 4.8 3.3 2.0 0 0 4.2 12.9 2.9 1.8 12.4 3.3 3.3 2.6 2.6 3.3 0 0 0 5.1 6.2 6.2 0 0.8 0.9 13.2 6.2 0 1.9 1.8 8.7 2.6 0 2.6 0 0.7 0.9 13.2 1.9 1.8 28.0 13.2 1.0 0 1.7 1.1 28.0 -18.3 2.5 0.7 18.1 18.1 11.7 11.7 0 8.1 0 0 0 0 0 0 0 2.5 2.5 0 11.7 11.5 12.9 0 4.0 1.7 0 0 3.3 3.3 3.3 8.1 4.0 18.0 (0) (15.4) (2.2) (4.0) 19.1 18.1 18.0 (0) AC10.2 Primary side ground 0.8V/0.68V 8.5V/7.9V 5V VCC ENB 5V REF 3.5V 4V RT CT OSC +0.24V R S QB Q ENB OUT PUT 16.5V/9V UVLO 15.5V 15.5V 5.2 A 0.95mA PWM 0.8V Dmax FA5510: 46% FA5511: 70% 5V Controlled block FB (2) REF (7) CS(8) VCC(6) OUT (5) GND (4) IS+(3) RT(1) FF IC2: FA5511N-D1-TE1 CMOS IC for switching power supply control IC15: NJM79M05FA Voltage regulator COMMON OUTPUT INPUT IC8: NJM78M12FA Voltage regulator INPUT OUTPUT COMMON IC14: NJM78M05FA 3-terminal positive voltage regulator IN OUT GND IC12: NJM7805FA 3-terminal positive voltage regulator INPUT OUTPUT GND IC4, 10, 11: TPS54331 3A, 28V input, STEP DPWN SWIFTTM DC/DC converter with ECO-MODETM ECO-MODE ™ Minimum Clamp Error Amplifier Shutdown Shutdown Logic Shutdown Voltage Reference 4 SS 6 COMP 5 VSENSE 3 EN 2 VIN 1 BOOT 8 PH 7 GND ∑ + + – Discharge Logic Maximum Clamp S Q 1.25V Enable Threshold Enable Comparator Thermal Shutdown 165C Boot UVLO Boot Charge VSENSE Slope Compensation Oscillator 12A/V Current Sense PWM Latch PWM Comparator Frequency Shift gm = 92μA/V DC gain = 800 V/V BW = 2.7MHz Gate Logic Drive R 80m-ohms 2.1V 0.8V 2 μA 1 μA 2 μA 2 k-ohms CTL 1 2 3 4 5 Vcc GND TSD OCP Vref - + Driver VOUT C IC5: BA00JC5WT-V5 Voltage regulator IC6: BD9781HFP-TR Flexible step-down switching regulator VIN INV FB RT GND SW EN/SYNC SOFT START Vref SYNC ON/OFF OSC Vref ERROR AMP PWM COMPARATOR TSD VIN LATCH RESET CURENT LIMIT L:OFF H:ON 1 6 5 3 7 DRIVER 2 4 IC13: LMV431AIMF Low voltage adjustable precision shunt regulator REF CATHODE ANODE IC7: NJM431U Adjustable precision shunt regulator ANODE REFERENCE CATHODE 1 2 3 AC IN POWER TRANSFORMER YMC-500 to MAIN 2/5 to MAIN 2/5 to MAIN 2/5 to MAIN 2/5 to MAIN 3/5 YMC-700 to DIGITAL_CB381 Page 82 K9 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com ★ All voltages are measured with a 10MΩ/V DC electronic voltmeter. ★ Components having special characteristics are marked ⚠ and must be replaced with parts having specifications equal to those originally installed. ★ Schematic diagram is subject to change without notice. A 1 2 3 4 5 6 7 8 9 10 B C D E F G H I J K L M N 85 MAIN 2/5 YMC-700/YMC-500 CB50 CB51 IC53 IC52 IC51 IC55 IC55 IC54 IC54 5.0 0 2.7 5.0 0 2.7 2.7 5.0 0 5.0 2.3 2.0 3.3 3.3 3.3 1.5 0 1.7 1.7 1.7 1.7 1.7 1.7 0 0 3.3 0 3.3 0 0 0 0 3.3 3.3 3.3 0 0 -5.0 0.8 0 0 0 0 0.8 -5.0 5.0 12.0 3.3 0 0 14.0 0 14.0 14.0 14.0 14.0 14.0 14.0 14.0 14.0 14.0 0 3.3 0 0 0 0 0 0 0 3.3 0 0 0 12.0 12.0 1.7 0 1.7 3.3 12.0 0 0 28.0 28.0 14.0 0 0 14.0 28.0 0 28.0 14.0 0 0 14.0 28.0 28.0 0 0 12.0 0 12.0 3.3 0 0 3.3 0 0 0 0 0 0 0 3.3 0 0 0 12.0 12.0 1.7 0 1.7 3.3 12.0 0 0 28.0 28.0 14.0 0 0 14.0 28.0 0 28.0 14.0 0 0 14.0 28.0 28.0 0 0 12.0 0 12.0 3.3 0 0 3.3 0 0 0 0 0 0 0 3.3 0 0 0 12.0 12.0 1.7 0 0 3.3 12.0 0 0 28.0 28.0 0 0 0 0 28.0 0 28.0 14.0 0 0 14.0 28.0 28.0 0 12.0 0 -5.0 0 0 -5.0 0 SUB WOOFER FRONT L CENTER SURROUND L IC54: NJM4565M Dual operational amplifier 8 2, 6 3, 5 1, 7 4 V+ –INPUT +INPUT V– OUTPUT IC51-53: TAS5342LDDV 100 W stereo digital amplifier power stage OTW 2 5 15 14 13 7 17 18 16 8 6 SD M1 M2 M3 RESET_AB RESET_CD PWM_D PWM_C PWM_B PWM_A VDD VREG AGND GND OC_ADJ GVDD_D BST_D PVDD_D OUT_D GND_D GVDD_C BST_C PVDD_C OUT_C GND_C GVDD_B BST_B PVDD_B OUT_B GND_B GVDD_A BST_A PVDD_A OUT_A GND_A Internal Pullup Resistors to VREG Protection and I/O Logic Under- voltage Protection Power On Reset Temp. Sense VREG 4 4 Isense PWM Rcv. Ctrl. Timing PWM Rcv. Ctrl. Timing Gate Drive Gate Drive BTL/PBTL-Configuration Pulldown Resistor BTL/PBTL-Configuration Pulldown Resistor BTL/PBTL-Configuration Pulldown Resistor BTL/PBTL-Configuration Pulldown Resistor Ctrl. Timing Gate Drive Ctrl. Timing Gate Drive PWM Rcv. PWM Rcv. Overload Protection 21 12 11 10 9 23 28 24 26, 27 29 22 33 32 31 30 1 36 34 35 37 44 39 43 40, 41 38 1 2 3 5 4 7 6 8 1. A OUTPUT 2. A-INPUT 3. A+INPUT 4. GND 5. B+INPUT 6. B-INPUT 7. B OUTPUT 8. V+ IC55: NJM2904M (TE3) Single supply dual operational amplifier A B SPEAKERS CENTER SURROUND L L R R FRONT DIGITAL AMPLIFIER DIGITAL AMPLIFIER DIGITAL AMPLIFIER YMC-500 to MAIN 1/5 to MAIN 3/5 YMC-700 to DIGITAL_CB384 Page 82 F9 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com ★ All voltages are measured with a 10MΩ/V DC electronic voltmeter. ★ Components having special characteristics are marked ⚠ and must be replaced with parts having specifications equal to those originally installed. ★ Schematic diagram is subject to change without notice. A 1 2 3 4 5 6 7 8 9 10 B C D E F G H I J K L M N YMC-700/YMC-500 86 MAIN 3/5 IC102 W1000 CB100 CB101 IC102 IC103 IC103 IC104 0 0 0 -5.0 5.0 0 5.0 -5.0 0 0 5.0 0 0 0 0 0 0 0 0 0 5.0 -5.0 0 0 0 0 0 -5.0 0 0 5.0 0 0 5.0 2.5 2.5 0 0 0 0 0 0 0 10.7 12.0 0 10.0 5.1 5.1 5.1 0 0 0 5.1 0 0 0 0 0 0 5.1 5.1 5.1 3.3 0 1.9 3.3 0 3.3 0 0 0 0 2.5 0 2.5 0 0 0 5.1 0 5.1 0 5.1 0 10.7 10.0 ANALOG IN SUB WOOFER IC103: NJM4565M Dual operational amplifier 8 2, 6 3, 5 1, 7 4 V+ –INPUT +INPUT V– OUTPUT 1 2 3 4 8 7 6 5 1OUT 1IN– 1IN+ VCC– VCC+ 2OUT 2IN– 2IN+ OUT VCC– VCC+ 36 pF 37 pF 14 pF 7 pF 15 460 15 IN+ IN IC102: NE5532DR Dual low-noise operational amplifiers IC104: TC74HC4052AF Analog multiplexer/demultiplexer 16 VCC 6 INH 10 A 9 B 8 GND 7 VEE 12 0X 14 1X 15 2X 11 3X 1 0Y 5 1Y 2 2Y 4 3Y LEVEL CONVERTER BINARY TO 1-OF-4 DECODER WITH INHIBIT SW SW SW SW SW SW SW SW 13 X-COM 3 Y-COM INHIBIT 0 0 0 0 1 B 0 0 1 1 X A 0 1 0 1 X 0x, 0y 1x, 1y 2x, 2y 3x, 3y NONE INPUT SELECTOR OUTPUT AUDIO IN SUBWOOFER YMC-500 to MAIN 5/5 to MAIN 4/5 to MAIN 1/5 to MAIN 5/5 to MAIN 4/5 to MAIN 4/5 to MAIN 2/5 YMC-700 to DIGITAL_CB385 To FM TUNER Page 82 I9 to OPERATION (2)_CB151 Page 83 B2 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com ★ All voltages are measured with a 10MΩ/V DC electronic voltmeter. ★ Components having special characteristics are marked ⚠ and must be replaced with parts having specifications equal to those originally installed. ★ Schematic diagram is subject to change without notice. A 1 2 3 4 5 6 7 8 9 10 B C D E F G H I J K L M N 87 MAIN 4/5 YMC-700/YMC-500 IC201 IC201 W2001 IC201 IC201 IC202 2.6 2.6 2.6 0 0 0 0 5.1 0 0 2.5 0 0 0 0 0 0 0 0 0 0 0 2.5 5.1 0 5.1 0 2.5 0 0 0.8 5.1 0 0 2.6 2.6 2.6 2.6 5.1 2.6 2.6 3.2 5.1 2.6 3.3 2.6 IC201: TC74HC4053AF Analog multiplexer/demultiplexer INPUT STATES INHIBIT 0 0 0 0 0 0 0 0 1 "ON" CHANNEL (S) 0X, 0Y, 0Z 1X, 0Y, 0Z 0X, 1Y, 0Z 1X, 1Y, 0Z 0X, 0Y, 1Z 1X, 0Y, 1Z 0X, 1Y, 1Z 1X, 1Y, 1Z NONE C 0 0 0 0 1 1 1 1 X B 0 0 1 1 0 0 1 1 X A 0 1 0 1 0 1 0 1 X BINARY TO 1-OF-8 DECODER WITH INHIBIT LEVEL CONVERTER VCC INHIBIT A B C GND VEE 0X 1X 0Y 1Y 0Z X-COM Z-COM Y-COM SW SW SW SW SW SW 11 6 16 10 9 8 7 12 13 2 5 3 1 14 15 4 IC202: NJM2580M (TE2) Single supply wide band 3 ch video amplifier 13 VOUT1 11 VOUT2 9 VOUT3 8 VSAG 10 V+3 14 V+1 12 V+2 2 GND1 4 GND2 6 GND3 7 PowerSave 5 VIN3 1 VIN1 3 VIN2 75 Driver 6dB AMP BIAS 75 Driver 6dB AMP BIAS 75 Driver 6dB AMP CLAMP REF VIDEO IN INPUT SELECTOR YMC-500 to MAIN 3/5 to MAIN 3/5 to MAIN 3/5 to MAIN 5/5 YMC-700 to DIGITAL_CB382 Page 82 B9 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com ★ All voltages are measured with a 10MΩ/V DC electronic voltmeter. ★ Components having special characteristics are marked ⚠ and must be replaced with parts having specifications equal to those originally installed. ★ Schematic diagram is subject to change without notice. A 1 2 3 4 5 6 7 8 9 10 B C D E F G H I J K L M N YMC-700/YMC-500 88 MAIN 5/5 CB251 1.9 1.4 DOCK No replacement part available. to MAIN 3/5 to MAIN 3/5 to MAIN 4/5 YMC-500 YMC-700 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com ★ All voltages are measured with a 10MΩ/V DC electronic voltmeter. ★ Components having special characteristics are marked ⚠ and must be replaced with parts having specifications equal to those originally installed. ★ Schematic diagram is subject to change without notice. A 1 2 3 4 5 6 7 8 9 10 B C D E F G H I J K L M N 89 WIFI YMC-700/YMC-500 IC601 CB601 IC602 0 0 0 3.3 0 3.3 0 3.3 3.3 3.4 3.3 3.3 5.1 0 5.1 0 3.4 3.4 0 5.1 0 0 3.4 0 0 0 3.4 0 0 3.3 3.3 0 0 0 3.3 3.3 3.3 0 0 0 0 3.3 5.1 5.1 0 0 0 0 0 0 2.9 0 0 0 0 3.4 3.4 0 0 VDD CE Pin No. 1 2, 5 3 4 6 Symbol VOUT GND CE NC VDD Description Output Pin of Voltage Regulator Ground Pin Chip Enable Pin No Connection Input Pin Vref 6 1 3 2,5 Current Limit VOUT GND IC602: R1172S331B-E2-F CMOS-based positive-voltage regulator IC No replacement part available. YMC-700 to DIGITAL_CB363 Page 80 H3 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 91 YMC-700/YMC-500 YMC-700/YMC-500 ABBREVIATIONS IN THIS LIST ARE AS FOLLOWS: C.A.EL.CHP : CHIP ALUMI.ELECTROLYTIC CAP C.CE : CERAMIC CAP C.CE.ARRAY : CERAMIC CAP ARRAY C.CE.CHP : CHIP CERAMIC CAP C.CE.ML : MULTILAYER CERAMIC CAP C.CE.M.CHP : CHIP MULTILAYER CERAMIC CAP C.CE.SAFTY : RECOGNIZED CERAMIC CAP C.CE.TUBLR : CERAMIC TUBULAR CAP C.CE.SMI : SEMI CONDUCTIVE CERAMIC CAP C.EL : ELECTROLYTIC CAP C.MICA : MICA CAP C.ML.FLM : MULTILAYER FILM CAP C.MP : METALLIZED PAPER CAP C.MYLAR : MYLAR FILM CAP C.MYLAR.ML : MULTILAYER MYLAR FILM CAP C.PAPER : PAPER CAPACITOR C.PLS : POLYSTYRENE FILM CAP C.POL : POLYESTER FILM CAP C.POLY : POLYETHYLENE FILM CAP C.PP : POLYPROPYLENE FILM CAP C.TNTL : TANTALUM CAP C.TNTL.CHP : CHIP TANTALUM CAP C.TRIM : TRIMMER CAP CN : CONNECTOR CN.BS.PIN : CONNECTOR,BASE PIN CN.CANNON : CONNECTOR,CANNON CN.DIN : CONNECTOR,DIN CN.FLAT : CONNECTOR,FLAT CABLE CN.POST : CONNECTOR,BASE POST COIL.MX.AM : COIL,AM MIX COIL.AT.FM : COIL,FM ANTENNA COIL.DT.FM : COIL,FM DETECT COIL.MX.FM : COIL,FM MIX COIL,OUTPT : OUTPUT COIL DIOD.ARRAY : DIODE ARRAY DIODE.BRG : DIODE BRIDGE DIODE.CHP : CHIP DIODE DIODE.VAR : VARACTOR DIODE DIOD.Z.CHP : CHIP ZENER DIODE DIODE.ZENR : ZENER DIODE DSCR.CE : CERAMIC DISCRIMINATOR FER.BEAD : FERRITE BEADS FER.CORE : FERRITE CORE FET.CHP : CHIP FET FL.DSPLY : FLUORESCENT DISPLAY FLTR.CE : CERAMIC FILTER FLTR.COMB : COMB FILTER MODULE FLTR.LC.RF : LC FILTER,EMI GND.MTL : GROUND PLATE GND.TERM : GROUND TERMINAL HOLDER.FUS : FUSE HOLDER IC.PRTCT : IC PROTECTOR JUMPER.CN : JUMPER CONNECTOR JUMPER.TST : JUMPER,TEST POINT L.DTCT : LIGHT DETECTING MODULE L.EMIT : LIGHT EMITTING MODULE LED.DSPLY : LED DISPLAY LED.INFRD : LED,INFRARED MODUL.RF : MODULATOR,RF PHOT.CPL : PHOTO COUPLER PHOT.INTR : PHOTO INTERRUPTER PHOT.RFLCT : PHOTO REFLECTOR PIN.TEST : PIN,TEST POINT PLST.RIVET : PLASTIC RIVET R.ARRAY : RESISTOR ARRAY R.CAR. : CARBON RESISTOR R.CAR.CHP : CHIP RESISTOR R.CAR.FP : FLAME PROOF CARBON RESISTOR R.FUS : FUSABLE RESISTOR R.MTL.CHP : CHIP METAL FILM RESISTOR R.MTL.FLM : METAL FILM RESISTOR R.MTL.OXD : METAL OXIDE FILM RESISTOR R.MTL.PLAT : METAL PLATE RESISTOR RSNR.CE : CERAMIC RESONATOR RSNR.CRYS : CRYSTAL RESONATOR R.TW.CEM : TWIN CEMENT FIXED RESISTOR R.CEMENT : CEMENT RESISTOR SCR.BND.HD : BIND HEAD B-TIGHT SCREW SCR.BW.HD : BW HEAD TAPPING SCREW SCR.CUP : CUP TIGHT SCREW SCR.TERM : SCREW TERMINAL SCR.TR : SCREW,TRANSISTOR SUPRT.PCB : SUPPORT,P.C.B. SURG.PRTCT : SURGE PROTECTOR SW.TACT : TACT SWITCH SW.LEAF : LEAF SWITCH SW.LEVER : LEVER SWITCH SW.MICRO : MICRO SWITCH SW.PUSH : PUSH SWITCH SW.RT.ENC : ROTARY ENCODER SW.RT.MTR : ROTARY SWITCH WITH MOTOR SW.RT : ROTARY SWITCH SW.SLIDE : SLIDE SWITCH TERM.SP : SPEAKER TERMINAL TERM.WRAP : WRAPPING TERMINAL THRMST.CHP : CHIP THERMISTOR TR.CHP : CHIP TRANSISTOR TR.DGT : DIGITAL TRANSISTOR TR.DGT.CHP : CHIP DIGITAL TRANSISTOR TRANS : TRANSFORMER TRANS.PULS : PULSE TRANSFORMER TRANS.PWR : POWER TRANSFORMER ASS’Y TUNER.AM : TUNER PACK,AM TUNER.FM : TUNER PACK,FM TUNER.PK : FRONT-ENDTUNER PACK VR : ROTARY POTENTIOMETER VR.MTR : POTENTIOMETER WITH MOTOR VR.SW : POTENTIOMETER WITH ROTARY SW VR.SLIDE : SLIDE POTENTIOMETER VR.TRIM : TRIMMER POTENTIOMETER • ELECTRICAL COMPONENT PARTS WARNING ● Components having special characteristics are marked ⚠ and must be replaced with parts having specifications equal to those originally installed. ■ REPLACEMENT PARTS LIST www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 92 YMC-700/YMC-500 YMC-700/YMC-500 Ref No. Part No. Description Markets Ref No. Part No. Description Markets P.C.B. DIGITAL * WR116700 P.C.B. DIGITAL (700) * WR117000 P.C.B. DIGITAL (500) CB311-313 WM462600 CN.HDMI 19P SE CB321 WM462600 CN.HDMI 19P SE CB361 WG939700 CN.USB 4P SE * CB362 WM297100 CN.LAN 6P 08B1-1X1T-06-F (700) * CB363 WA625700 CN.BS.PIN 14P SE (700) * CB381 VT619600 CN.BS.PIN 10P SE * CB382 VT873800 CN 10P * CB383 V7284000 CN.BS.PIN 17P SE * CB384-385 WC336500 CN.BS.PIN 27P SE * C3101 WR060900 C.EL.CHP 100uF 16V * C3102-3109 WP882000 C.CE.CHP 10uF 6.3V C3110-3120 US634100 C.CE.CHP 0.01uF 16V * C3121-3131 US625100 C.CE.CHP 0.100uF 10V * C3132 WJ932500 C.CE.CHP 1uF 6.3V * C3133-3140 US625100 C.CE.CHP 0.100uF 10V * C3142-3143 US625100 C.CE.CHP 0.100uF 10V * C3155-3159 US625100 C.CE.CHP 0.100uF 10V C3160 US060700 C.CE.CHP 7pF 50V B * C3161-3165 US625100 C.CE.CHP 0.100uF 10V * C3166 WP882000 C.CE.CHP 10uF 6.3V C3167-3168 US060900 C.CE.CHP 9pF 50V D * C3169-3171 US625100 C.CE.CHP 0.100uF 10V * C3172 WP882000 C.CE.CHP 10uF 6.3V * C3173 US625100 C.CE.CHP 0.100uF 10V C3174-3175 US634100 C.CE.CHP 0.01uF 16V * C3176-3177 US625100 C.CE.CHP 0.100uF 10V * C3178-3179 WP882000 C.CE.CHP 10uF 6.3V * C3180-3182 US625100 C.CE.CHP 0.100uF 10V * C3183 WP882000 C.CE.CHP 10uF 6.3V * C3184 US625100 C.CE.CHP 0.100uF 10V C3185 US634100 C.CE.CHP 0.01uF 16V C3186 US034820 C.CE.CHP 0.082uF 16V K C3187 US034390 C.CE.CHP 0.039uF 16V B C3188 VZ281900 C.CE.CHP 0.47uF 16V K C3189 VZ243400 C.CE.CHP 0.33uF 16V C3190-3191 US634100 C.CE.CHP 0.01uF 16V C3192 US062220 C.CE.CHP 220pF 50V B * C3193-3194 US625100 C.CE.CHP 0.100uF 10V C3195 US663100 C.CE.CHP 1000pF 50V C3196 US060800 C.CE.CHP 8pF 50V B * C3201-3203 WP882000 C.CE.CHP 10uF 6.3V * C3204 US625100 C.CE.CHP 0.100uF 10V C3205-3206 US634100 C.CE.CHP 0.01uF 16V * C3207 US625100 C.CE.CHP 0.100uF 10V C3208 US634100 C.CE.CHP 0.01uF 16V * C3209 US625100 C.CE.CHP 0.100uF 10V C3210 US634100 C.CE.CHP 0.01uF 16V * C3211 US625100 C.CE.CHP 0.100uF 10V C3212 US634100 C.CE.CHP 0.01uF 16V * C3213 US625100 C.CE.CHP 0.100uF 10V C3214 US634100 C.CE.CHP 0.01uF 16V * C3215 US625100 C.CE.CHP 0.100uF 10V C3216 US634100 C.CE.CHP 0.01uF 16V * C3217 US625100 C.CE.CHP 0.100uF 10V C3218 US634100 C.CE.CHP 0.01uF 16V * C3219 US625100 C.CE.CHP 0.100uF 10V C3220 US634100 C.CE.CHP 0.01uF 16V * C3221 US625100 C.CE.CHP 0.100uF 10V C3222 US634100 C.CE.CHP 0.01uF 16V * C3223 US625100 C.CE.CHP 0.100uF 10V C3224 WD758300 C.CE.CHP 10uF 10V * C3225 US625100 C.CE.CHP 0.100uF 10V * C3228 US625100 C.CE.CHP 0.100uF 10V * C3289 WR060900 C.EL.CHP 100uF 16V * C3290-3291 WP882000 C.CE.CHP 10uF 6.3V * C3292 WR058800 C.EL.CHP 22uF 10V * C3293 WR060900 C.EL.CHP 100uF 16V * C3294-3295 WP882000 C.CE.CHP 10uF 6.3V * C3296 WR058800 C.EL.CHP 22uF 10V * C3297 US625100 C.CE.CHP 0.100uF 10V * C3301 WR060900 C.EL.CHP 100uF 16V * C3302 WJ932500 C.CE.CHP 1uF 6.3V * C3303 WR060900 C.EL.CHP 100uF 16V * C3304 WR058800 C.EL.CHP 22uF 10V * C3305 WP882000 C.CE.CHP 10uF 6.3V * C3306 WJ932500 C.CE.CHP 1uF 6.3V * C3307 WP882000 C.CE.CHP 10uF 6.3V * C3309-3315 WP882000 C.CE.CHP 10uF 6.3V * C3318-3349 US625100 C.CE.CHP 0.100uF 10V C3351 US663100 C.CE.CHP 1000pF 50V C3356 US663100 C.CE.CHP 1000pF 50V C3371-3372 US663100 C.CE.CHP 1000pF 50V * C3378-3381 WJ932500 C.CE.CHP 1uF 6.3V C3392-3394 US634100 C.CE.CHP 0.01uF 16V * C3395 US625100 C.CE.CHP 0.100uF 10V * C3401-3404 WP882000 C.CE.CHP 10uF 6.3V * C3405 US625100 C.CE.CHP 0.100uF 10V C3407-3408 US061220 C.CE.CHP 22pF 50V B * C3409 US625100 C.CE.CHP 0.100uF 10V * C3411 US625100 C.CE.CHP 0.100uF 10V * C3413-3414 US625100 C.CE.CHP 0.100uF 10V * C3416-3425 US625100 C.CE.CHP 0.100uF 10V * C3427 US625100 C.CE.CHP 0.100uF 10V * C3429-3430 US625100 C.CE.CHP 0.100uF 10V * C3432 US625100 C.CE.CHP 0.100uF 10V * C3434 US625100 C.CE.CHP 0.100uF 10V * C3437-3439 US625100 C.CE.CHP 0.100uF 10V * C3441 US625100 C.CE.CHP 0.100uF 10V * C3443 US625100 C.CE.CHP 0.100uF 10V * C3445 WP882000 C.CE.CHP 10uF 6.3V * C3446-3449 WJ932500 C.CE.CHP 1uF 6.3V C3450-3452 US634100 C.CE.CHP 0.01uF 16V * C3453-3462 US625100 C.CE.CHP 0.100uF 10V * C3463 WJ932500 C.CE.CHP 1uF 6.3V * C3464-3465 US625100 C.CE.CHP 0.100uF 10V C3466 US634100 C.CE.CHP 0.01uF 16V * C3467 WR060900 C.EL.CHP 100uF 16V C3468 US061180 C.CE.CHP 18pF 50V B * C3469 WJ932500 C.CE.CHP 1uF 6.3V * C3470 US625100 C.CE.CHP 0.100uF 10V * C3471 WJ932500 C.CE.CHP 1uF 6.3V C3472-3473 US062220 C.CE.CHP 220pF 50V B ✻ New Parts ✻ New Parts YMC-700 YMC-500 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 93 YMC-700/YMC-500 YMC-700/YMC-500 Ref No. Part No. Description Markets Ref No. Part No. Description Markets P.C.B. DIGITAL * C3474 US625100 C.CE.CHP 0.100uF 10V * C3475-3476 WE475400 C.EL 100uF 6.3V * C3477 US625100 C.CE.CHP 0.100uF 10V * C3478-3484 WJ932500 C.CE.CHP 1uF 6.3V * C3485-3486 US625100 C.CE.CHP 0.100uF 10V * C3501-3518 US625100 C.CE.CHP 0.100uF 10V C3519 US663100 C.CE.CHP 1000pF 50V * C3520-3521 US625100 C.CE.CHP 0.100uF 10V C3522 US062220 C.CE.CHP 220pF 50V B * C3523 US625100 C.CE.CHP 0.100uF 10V C3524 US663100 C.CE.CHP 1000pF 50V * C3525-3526 US625100 C.CE.CHP 0.100uF 10V * C3601 WP882000 C.CE.CHP 10uF 6.3V * C3602 US625100 C.CE.CHP 0.100uF 10V * C3603 WP882000 C.CE.CHP 10uF 6.3V * C3604-3621 US625100 C.CE.CHP 0.100uF 10V C3622-3623 US634100 C.CE.CHP 0.01uF 16V C3624 US061120 C.CE.CHP 12pF 50V B C3625 US061220 C.CE.CHP 22pF 50V B * C3626 UB014220 C.CE.M.CHP 0.022uF 50V (700) * C3627 WP882000 C.CE.CHP 10uF 6.3V (700) * C3628-3637 US625100 C.CE.CHP 0.100uF 10V (700) * C3639 US625100 C.CE.CHP 0.100uF 10V (700) * C3641-3642 US625100 C.CE.CHP 0.100uF 10V (700) C3643 US634100 C.CE.CHP 0.01uF 16V (700) * C3644 WP882000 C.CE.CHP 10uF 6.3V (700) C3645 US634100 C.CE.CHP 0.01uF 16V (700) * C3646 WP882000 C.CE.CHP 10uF 6.3V (700) * C3647 US625100 C.CE.CHP 0.100uF 10V (700) * C3649 US625100 C.CE.CHP 0.100uF 10V (700) C3652 US062220 C.CE.CHP 220pF 50V B (700) C3654 US634100 C.CE.CHP 0.01uF 16V C3655 US062220 C.CE.CHP 220pF 50V B * C3656 US625100 C.CE.CHP 0.100uF 10V (700) C3658 US061120 C.CE.CHP 12pF 50V B (700) * C3659-3660 WR060900 C.EL.CHP 100uF 16V * C3661 WR060300 C.EL.CHP 22uF 16V * C3663 US625100 C.CE.CHP 0.100uF 10V (700) * C3664 WR060300 C.EL.CHP 22uF 16V * C3665-3668 US625100 C.CE.CHP 0.100uF 10V (700) C3669 US062220 C.CE.CHP 220pF 50V B (700) * C3670 WR060900 C.EL.CHP 100uF 16V (700) * C3681 US625100 C.CE.CHP 0.100uF 10V (700) * C3701-3704 WP882000 C.CE.CHP 10uF 6.3V * C3705-3706 US625100 C.CE.CHP 0.100uF 10V C3707 US663100 C.CE.CHP 1000pF 50V * C3708 US625100 C.CE.CHP 0.100uF 10V * C3709 WP882000 C.CE.CHP 10uF 6.3V * C3710 US625100 C.CE.CHP 0.100uF 10V C3711 US663100 C.CE.CHP 1000pF 50V * C3712 US625100 C.CE.CHP 0.100uF 10V * C3714 US625100 C.CE.CHP 0.100uF 10V C3715 US663100 C.CE.CHP 1000pF 50V * C3716-3718 US625100 C.CE.CHP 0.100uF 10V C3719 US663100 C.CE.CHP 1000pF 50V * C3720-3722 US625100 C.CE.CHP 0.100uF 10V * C3725 US625100 C.CE.CHP 0.100uF 10V * C3727 US625100 C.CE.CHP 0.100uF 10V * C3729-3735 US625100 C.CE.CHP 0.100uF 10V C3736 US062220 C.CE.CHP 220pF 50V B * C3737-3738 US625100 C.CE.CHP 0.100uF 10V C3739-3740 US663100 C.CE.CHP 1000pF 50V * C3741 US625100 C.CE.CHP 0.100uF 10V * C3742 WP882000 C.CE.CHP 10uF 6.3V * C3744-3745 US625100 C.CE.CHP 0.100uF 10V * C3746 WJ932500 C.CE.CHP 1uF 6.3V * C3747 US625100 C.CE.CHP 0.100uF 10V * C3748 WJ932500 C.CE.CHP 1uF 6.3V C3749 US663100 C.CE.CHP 1000pF 50V * C3750 WJ932500 C.CE.CHP 1uF 6.3V * C3751 US625100 C.CE.CHP 0.100uF 10V * C3752 WJ932500 C.CE.CHP 1uF 6.3V * C3753-3755 US625100 C.CE.CHP 0.100uF 10V * C3757 US625100 C.CE.CHP 0.100uF 10V C3758 US062220 C.CE.CHP 220pF 50V B * C3759-3760 US625100 C.CE.CHP 0.100uF 10V * C3761 WR060900 C.EL.CHP 100uF 16V * C3762-3763 WR058800 C.EL.CHP 22uF 10V * C3764 WP882000 C.CE.CHP 10uF 6.3V * C3765 WR060600 C.EL.CHP 47uF 16V * C3766-3769 US625100 C.CE.CHP 0.100uF 10V C3770 US062220 C.CE.CHP 220pF 50V B * C3775 WP882000 C.CE.CHP 10uF 6.3V * C3776 US625100 C.CE.CHP 0.100uF 10V C3777 US062220 C.CE.CHP 220pF 50V B * C3778 US625100 C.CE.CHP 0.100uF 10V * C3779 WP882000 C.CE.CHP 10uF 6.3V C3780-3781 US634100 C.CE.CHP 0.01uF 16V * C3782-3785 US625100 C.CE.CHP 0.100uF 10V C3791 US634100 C.CE.CHP 0.01uF 16V * C3792-3797 US625100 C.CE.CHP 0.100uF 10V * C3798 WP882000 C.CE.CHP 10uF 6.3V * C3799 US625100 C.CE.CHP 0.100uF 10V * C3801 WJ932500 C.CE.CHP 1uF 6.3V * C3802 US625100 C.CE.CHP 0.100uF 10V * C3803 WR058800 C.EL.CHP 22uF 10V * C3804 US625100 C.CE.CHP 0.100uF 10V * C3805 WR058800 C.EL.CHP 22uF 10V * C3806 US662120 C.CE.CHP 120pF 50V C3807 US062220 C.CE.CHP 220pF 50V B * C3808 WP882000 C.CE.CHP 10uF 6.3V * C3809 US625100 C.CE.CHP 0.100uF 10V * C3810-3811 US662120 C.CE.CHP 120pF 50V * C3812 US625100 C.CE.CHP 0.100uF 10V C3813-3815 US062220 C.CE.CHP 220pF 50V B * C3816-3821 US662120 C.CE.CHP 120pF 50V * C3828-3832 US662120 C.CE.CHP 120pF 50V C3835 US663100 C.CE.CHP 1000pF 50V * C3838 US662120 C.CE.CHP 120pF 50V * C3839 WP882000 C.CE.CHP 10uF 6.3V * C3841-3845 US662120 C.CE.CHP 120pF 50V * C3848-3853 US662120 C.CE.CHP 120pF 50V * C3855-3868 US662120 C.CE.CHP 120pF 50V * C3869 US625100 C.CE.CHP 0.100uF 10V ✻ New Parts ✻ New Parts YMC-700 YMC-500 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 94 YMC-700/YMC-500 YMC-700/YMC-500 Ref No. Part No. Description Markets Ref No. Part No. Description Markets * C3870 WR058500 C.EL.CHP 1000uF 6.3V * C3871 US625100 C.CE.CHP 0.100uF 10V C3873 US062220 C.CE.CHP 220pF 50V B * C3874 US625100 C.CE.CHP 0.100uF 10V C3875-3876 US062220 C.CE.CHP 220pF 50V B * C3877-3881 US662120 C.CE.CHP 120pF 50V * C4101 WP882000 C.CE.CHP 10uF 6.3V C4211 US062220 C.CE.CHP 220pF 50V B * C4217 WP882000 C.CE.CHP 10uF 6.3V * C4401-4403 US625100 C.CE.CHP 0.100uF 10V * C4404 WP882000 C.CE.CHP 10uF 6.3V * C4405-4408 WJ932500 C.CE.CHP 1uF 6.3V C4409-4411 US634100 C.CE.CHP 0.01uF 16V * C4412-4415 US625100 C.CE.CHP 0.100uF 10V C4701 US061220 C.CE.CHP 22pF 50V B * C4702 US625100 C.CE.CHP 0.100uF 10V C4703 US634100 C.CE.CHP 0.01uF 16V * C4704 US625100 C.CE.CHP 0.100uF 10V C4705 US062220 C.CE.CHP 220pF 50V B * C4706 US625100 C.CE.CHP 0.100uF 10V C4708-4709 US060900 C.CE.CHP 9pF 50V D * C4710-4712 WP882000 C.CE.CHP 10uF 6.3V * C4714 WB573700 C.MYLA.CHP 0.1uF 16V * C4715 WB572900 C.MYLA.CHP 0.022uF 16V * C4716 WR060900 C.EL.CHP 100uF 16V * C4717 WR058800 C.EL.CHP 22uF 10V * C4721 US625100 C.CE.CHP 0.100uF 10V * C4722 WR060600 C.EL.CHP 47uF 16V * C4724 WR060300 C.EL.CHP 22uF 16V * C4801-4812 US625100 C.CE.CHP 0.100uF 10V * C4814-4815 US625100 C.CE.CHP 0.100uF 10V * C4825-4826 US625100 C.CE.CHP 0.100uF 10V * C4831-4832 US625100 C.CE.CHP 0.100uF 10V * C4836 US625100 C.CE.CHP 0.100uF 10V * C4851-4856 US625100 C.CE.CHP 0.100uF 10V * C4859 US625100 C.CE.CHP 0.100uF 10V * C4861-4864 US625100 C.CE.CHP 0.100uF 10V * C4871-4878 US625100 C.CE.CHP 0.100uF 10V * C4881-4887 US625100 C.CE.CHP 0.100uF 10V * D3101-3124 WP385600 PESD PESD0603-240 D3125-3133 WJ586300 VARISTOR SDV1608H100C050YPT D3209-3212 WJ586300 VARISTOR SDV1608H100C050YPT D3213 V2376600 DIODE.SHOT RB500V-40 D3214-3217 VT332900 DIODE 1SS355 D3219 VT332900 DIODE 1SS355 D3301 VT332900 DIODE 1SS355 D3303 VT332900 DIODE 1SS355 D3402 VT332900 DIODE 1SS355 D3404 VS597600 DIODE.CHP RB160L-40 TE25 D3601-3602 VT332900 DIODE 1SS355 D3705-3706 VT332900 DIODE 1SS355 D3801 VU171400 DIODE.ZENR UDZS3.3BTE-17 3.3V D3802 VT332900 DIODE 1SS355 D3804-3810 VT332900 DIODE 1SS355 D3812 VU171400 DIODE.ZENR UDZS3.3BTE-17 3.3V D3813 VT332900 DIODE 1SS355 G3801-3804 WB438000 TERM.GND M4 SD00433-21 * IC321 YA488A00 IC ADV7510BSTZ-225 IC323 X6123A00 IC SN74LV157APWR IC324 X7741A00 IC NJM2867F3-05(TE1) IC326-327 X7887A00 IC R1172S181B-E2-F IC332 X9625A00 IC M12L64164A-5TG IC333 X7195A00 IC R1172S121D-E2-F * IC334 YA698A00 IC 74LVC3GU04DP INV * IC342-343 YA478A00 IC K4S560832J-UC75000 * IC344 YA604D00 IC.MEMORY K8P6415UQB-PI4B000 (written) IC345 X6611A00 IC SN74LV123APWR * IC346 YA354A00 IC 74LVC08APW AND * IC347 YA355A00 IC 74LVC14APW INV * IC348 YA356A00 IC 74LVC32APW OR * IC349 XZ286A00 IC 74LVC245APW118 IC351 X8813A00 IC MB87L8760 IC352 X2709A00 IC SN74AHCT245PWR * IC353 YA357A00 IC 74LVC574APW OCTAL IC354 X9439A00 IC SN74AHCT574PWR * IC356 YA357A00 IC 74LVC574APW OCTAL * IC362 YA477A00 IC LAN9217-MT (700) IC363 X8096A00 IC R5523N001A-TR-F * IC365 YA382A00 IC NJM2386DL3-05(TE1) * IC366 YA481A00 IC TE4300PF (700) IC372 X9625A00 IC M12L64164A-5TG * IC373 YA605D00 IC.MEMORY MX29LV160CBTC-70G (written) * IC374 YA399A00 IC LC89058WD-E IC375 X7357A00 IC PCM1803DBR * IC376 X9716A00 IC TAS5086 * IC378 YA354A00 IC 74LVC08APW AND IC379 X3936A00 IC SN74LVU04APWR IC381 X6905A00 IC ADC084S021CIMM IC382 X5875A00 IC SN74LV4051APWR * IC383 YA486A00 IC S3F80JBBWS-QZ8B * IC384 YA382A00 IC NJM2386DL3-05(TE1) * IC385 XZ286A00 IC 74LVC245APW118 * IC386 YA583A00 IC 74LVC125APW * IC441-444 XZ286A00 IC 74LVC245APW118 * IC445 YA398A00 IC.MEMORY LE25LA322M-TLM-E * IC446 YA356A00 IC 74LVC32APW OR * IC447 YA351A00 IC 74LVC00APW NAND * IC448-450 YA350A00 IC 74LVC1G08GW AND IC471 X7195A00 IC R1172S121D-E2-F IC472-473 XV894A00 IC TC74VHC153FT MULTI * IC474 YA354A00 IC 74LVC08APW AND * IC478 YA358A00 IC 74LVC3G04DP INV * JK381-382 WP412700 JACK.MINI LGA6507-0100 PJ371 V8795700 JACK.PIN 1P Q3101-3106 VQ986700 TR 2SC4081 T106 Q3401 WE736300 FET RTQ040P02 * Q3801-3803 WJ195200 TR 2SA1015M Y,GR Q3804-3805 VQ986700 TR 2SC4081 T106 Q3807 WE736300 FET RTQ040P02 ST381 WA789600 SCR.TERM M3 U371 WN333200 CN.PHOTO.R 1P JSR1165 XL311-312 VZ772700 RSNR.CRYS 28.63636MHz XL331 WK841200 RESONATOR 27MHz DSO321SRAB XL341 WB551700 RSNR.CRYS 16.666MHz SMD-49 P.C.B. DIGITAL ✻ New Parts ✻ New Parts YMC-700 YMC-500 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 95 YMC-700/YMC-500 YMC-700/YMC-500 Ref No. Part No. Description Markets Ref No. Part No. Description Markets * XL361 WQ853200 RESONATOR 25MHz (700) XL362 WG538400 RSNR.CRYS 12MHz XL371 V3625700 RSNR.CRYS 24.576MHz XL381 WA782500 RSNR.CE 8MHz * WS216900 DAMPER 5x6x11 * WR117700 P.C.B. OPERATION CB151 VB858400 CN.BS.PIN 5P CB152 VH904200 CN.BS.PIN 14P CB153 VB858300 CN.BS.PIN 4P * CB154 V7284000 CN.BS.PIN 17P SE CB171 VQ960700 CN 4P CB172 VQ962500 CN.BS.PIN 4P C1501-1502 US135100 C.CE.CHP 0.1uF 16V C1503 US061330 C.CE.CHP 33pF 50V B C1505 US062100 C.CE.CHP 100pF 50V B C1507 US063100 C.CE.CHP 1000pF 50V B C1508-1509 US135100 C.CE.CHP 0.1uF 16V C1551 UM397220 C.EL 22uF 25V C1552 UM397100 C.EL 10uF 16V C1553 UM397220 C.EL 22uF 25V C1554 UM397470 C.EL 47uF 16V C1555 UM397220 C.EL 22uF 25V C1556 UM397100 C.EL 10uF 16V C1603-1604 US135100 C.CE.CHP 0.1uF 16V C1605-1606 US064100 C.CE.CHP 0.01uF 50V B C1607-1608 US063100 C.CE.CHP 1000pF 50V B C1609 WK004400 C.CE.M.CHP 10uF 16V C1610 US061270 C.CE.CHP 27pF 50V B C1611 US145100 C.CE.CHP 0.1uF 25V C1612-1614 WK004400 C.CE.M.CHP 10uF 16V C1651 UM397470 C.EL 47uF 16V C1701 US145100 C.CE.CHP 0.1uF 25V C1702 US062100 C.CE.CHP 100pF 50V B C1703 US135100 C.CE.CHP 0.1uF 16V C1704 US060200 C.CE.CHP 2pF 50V B C1705 US063100 C.CE.CHP 1000pF 50V B C1706 WK004400 C.CE.M.CHP 10uF 16V C1707 US061330 C.CE.CHP 33pF 50V B C1708 US145100 C.CE.CHP 0.1uF 25V C1709 WK004400 C.CE.M.CHP 10uF 16V C1710 US064100 C.CE.CHP 0.01uF 50V B C1711 WK004400 C.CE.M.CHP 10uF 16V C1712 US063470 C.CE.CHP 4700pF 50V B C1714 WK004400 C.CE.M.CHP 10uF 16V C1721 US135100 C.CE.CHP 0.1uF 16V C1751 UM397470 C.EL 47uF 16V C1752 UM397100 C.EL 10uF 16V C1851-1854 US064100 C.CE.CHP 0.01uF 50V B C1901-1902 US064100 C.CE.CHP 0.01uF 50V B C1903 US061330 C.CE.CHP 33pF 50V B D1501-1502 VU992100 DIODE.ZENR MAZ8047GLL 4.6V D1503 VU992600 DIODE.ZENR MAZ8051GML 5.1V D1601-1602 WK151100 LED.CHP SMLE12BC7T BLUE D1603 V9634300 DIODE.SHOT RB551V-30 TAPING D1701 WF877600 DIODE.PHOT PD413PI D1702 V9634300 DIODE.SHOT RB551V-30 TAPING D1703 V2598200 LED SIR-505ST D1704 V9634300 DIODE.SHOT RB551V-30 TAPING IC151 X7378A00 IC NJM4565M(TE1) * IC161 XS271A00 IC BA4510F-E2 OPAMP * IC171 XS271A00 IC BA4510F-E2 OPAMP JK151 WC814400 JACK.MNI JY-3554-01-130 PN151-152 V9637500 PIN L=70 #18 PN191 V9637500 PIN L=70 #18 Q1601-1604 WC529400 TR KTC3875S Y GR RTK Q1701 WC398300 TR 2N5551S-RTK/P ST151-152 WA789700 SCR.TERM D3.5 ST171 WA789700 SCR.TERM D3.5 * SW161 WD448700 SW.RT.ENC XREB12104PVB25FINB SW185-192 WD483100 SW.TACT SKRGAAD010 U1701 WK918500 L.DTCT GP1UE271RKVF * WS027900 LED.HOLDER LED3-2B PIN * WR117400 P.C.B. MAIN CB1-2 WN077700 CLIP.FUSE CLIP PFC5000-0202F CB50 V6313400 CN.BS.PIN 27P TE CB100 VM923600 CN.BS.PIN 13P CB101 V6313400 CN.BS.PIN 27P TE ⚠ C1 V5877700 C.MYLAR 0.22uF 250V ⚠ C2-3 WH036100 C.CE.SEFTY 2200pF 250V ⚠ * C4 WN826300 C.CE.SAFTY 0.01uF 250V ⚠ C5 WJ605000 C.MYLAR 0.01uF 50V J C6 US064100 C.CE.CHP 0.01uF 50V B C8 UR759220 C.EL 2200uF 35V C9 VZ281900 C.CE.CHP 0.47uF 16V K ⚠ C10 V5877700 C.MYLAR 0.22uF 250V C11 US064100 C.CE.CHP 0.01uF 50V B C12-13 VZ243300 C.CE.CHP 0.22uF 16V C14 UR866100 C.EL 1uF 50V C15 US064100 C.CE.CHP 0.01uF 50V B C16 WF411500 C.EL 820uF 200V C17 WJ047200 C.EL 22uF 50V C18 WJ322400 C.CE.M.CHP 0.01uF 250V C19 UR837100 C.EL 10uF 16V ⚠ * C21 WQ857000 C.CE.SAFTY 680pF 250V C22 V9885300 C.CE.CHP 10uF 16V C23 US064150 C.CE.CHP 0.015uF 50V B C24 US065100 C.CE.CHP 0.1uF 50V B * C26 WP381900 C.CE.M.CHP 4.7uF 50V C27 UR266100 C.EL 1uF 50V C28 US065100 C.CE.CHP 0.1uF 50V B C29 US063270 C.CE.CHP 2700pF 50V B * C30 WH777900 C.EL 1000uF 35V * C31 WQ072600 C.EL 220uF 35V C32 US063680 C.CE.CHP 6800pF 50V B C33 WK413800 C.CE.M.CHP 1000pF 250V C34 WH771300 C.EL 100uF 10V * C35 WN816700 C.EL 1500uF 35V * C37 WQ757300 C.CE.CHP 47uF 6.3V P.C.B. DIGITAL, P.C.B. OPERATION and P.C.B. MAIN ✻ New Parts ✻ New Parts YMC-700 YMC-500 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 96 YMC-700/YMC-500 YMC-700/YMC-500 Ref No. Part No. Description Markets Ref No. Part No. Description Markets C39 US065100 C.CE.CHP 0.1uF 50V B C41-42 V9885300 C.CE.CHP 10uF 16V C43 US035100 C.CE.CHP 0.1uF 16V B C44-45 US064150 C.CE.CHP 0.015uF 50V B C46 US065100 C.CE.CHP 0.1uF 50V B * C47 WQ072600 C.EL 220uF 35V C48-50 US065100 C.CE.CHP 0.1uF 50V B C52 UR838100 C.EL 100uF 16V C54-57 US065100 C.CE.CHP 0.1uF 50V B C58 UR838100 C.EL 100uF 16V C59 US064100 C.CE.CHP 0.01uF 50V B C60 US063270 C.CE.CHP 2700pF 50V B C61-62 US065100 C.CE.CHP 0.1uF 50V B C63-64 UR838100 C.EL 100uF 16V * C67 WP381900 C.CE.M.CHP 4.7uF 50V * C68 WQ614300 C.CE.CHP 22uF 10VE * C69 WQ757300 C.CE.CHP 47uF 6.3V C70 WH138300 C.EL 1000uF 25V C71 US063100 C.CE.CHP 1000pF 50V B * C73 UR259680 C.EL 6800uF 35V * C75 WN816700 C.EL 1500uF 35V C76-78 US065100 C.CE.CHP 0.1uF 50V B C79 US061270 C.CE.CHP 27pF 50V B * C80 WQ757300 C.CE.CHP 47uF 6.3V C81 US065100 C.CE.CHP 0.1uF 50V B C82 US061470 C.CE.CHP 47pF 50V B * C83 WQ614300 C.CE.CHP 22uF 10VE C84 US065100 C.CE.CHP 0.1uF 50V B C85 US061150 C.CE.CHP 15pF 50V B * C86-87 WQ757300 C.CE.CHP 47uF 6.3V * C500 WJ605700 C.MYLAR 0.039uF 50V C503 US046100 C.CE.CHP 1uF 25V * C504 WJ605200 C.MYLAR 0.015uF 50V * C507 WJ605200 C.MYLAR 0.015uF 50V C511 UR867100 C.EL 10uF 50V * C512 WN951300 C.EL 10uF 16V C515 VE326800 C.MYLAR 0.47uF 50V * C516-519 WN951300 C.EL 10uF 16V C520-525 US135100 C.CE.CHP 0.1uF 16V C528-533 US135100 C.CE.CHP 0.1uF 16V C534 US065100 C.CE.CHP 0.1uF 50V B * C535-543 UB044330 C.CE.M.CHP 0.033uF 50V C544-554 US065100 C.CE.CHP 0.1uF 50V B * C555-557 UB044330 C.CE.M.CHP 0.033uF 50V C568-572 US065100 C.CE.CHP 0.1uF 50V B * C578-580 WR772600 C.EL 470uF 35V C581-585 VE326800 C.MYLAR 0.47uF 50V C589-598 VE326000 C.MYLAR 0.1uF 50V * C599-600 WR772600 C.EL 470uF 35V C603-612 US063100 C.CE.CHP 1000pF 50V B C613-622 US064100 C.CE.CHP 0.01uF 50V B * C623 WH773000 C.EL 33uF 16V * C624 WR114200 C.EL 33uF 16V * C625 WN951400 C.EL 22uF 16V C626-627 US135100 C.CE.CHP 0.1uF 16V * C628-629 WJ603700 C.MYLAR 1000pF 50V C630-633 US135100 C.CE.CHP 0.1uF 16V C635-636 US135100 C.CE.CHP 0.1uF 16V C637 UR866100 C.EL 1uF 50V C1000 US064100 C.CE.CHP 0.01uF 50V B C1001 US135100 C.CE.CHP 0.1uF 16V C1002-1004 US062100 C.CE.CHP 100pF 50V B C1005-1006 US062220 C.CE.CHP 220pF 50V B C1007 US062100 C.CE.CHP 100pF 50V B C1008-1009 UR867100 C.EL 10uF 50V C1010 US062100 C.CE.CHP 100pF 50V B C1011-1012 US135100 C.CE.CHP 0.1uF 16V C1013 UR837470 C.EL 47uF 16V C1014-1015 UR867100 C.EL 10uF 50V C1016 UR837470 C.EL 47uF 16V C1025-1026 US135100 C.CE.CHP 0.1uF 16V C1029-1030 UR837100 C.EL 10uF 16V C1032 US135100 C.CE.CHP 0.1uF 16V C1034 US135100 C.CE.CHP 0.1uF 16V C1042-1043 UR837100 C.EL 10uF 16V C1049-1051 US135100 C.CE.CHP 0.1uF 16V C2001-2003 US135100 C.CE.CHP 0.1uF 16V C2004-2007 WD758300 C.CE.CHP 10uF 10V C2008 US135100 C.CE.CHP 0.1uF 16V C2009-2011 US064100 C.CE.CHP 0.01uF 50V B C2401-2402 UR818470 C.EL 470uF 6.3V C2403-2408 WD758300 C.CE.CHP 10uF 10V C2409-2410 UR818470 C.EL 470uF 6.3V C2411 UR837470 C.EL 47uF 16V C2412-2414 UR818470 C.EL 470uF 6.3V C2502 US064100 C.CE.CHP 0.01uF 50V B C2505-2510 US062220 C.CE.CHP 220pF 50V B C2903-2904 UR837100 C.EL 10uF 16V D1-2 WC398800 DIODE KDS160-RTK ⚠ D3 VR253700 DIODE.BRG S1NB20 1A 200V D4 VT332900 DIODE 1SS355 ⚠ D5 VN953300 DIODE.BRG D5SBA60 5A 600V D6 VT332900 DIODE 1SS355 D7 VN478200 DIODE D1NL20U D8 VT332900 DIODE 1SS355 D9 VV463000 DIODE.CHP 1.1A 200V D1FL20U D10 WJ459300 DIODE D1FK60-5063 D11 VU999500 DIODE.ZENR MAZ8270GML 27.0V D12 VT332900 DIODE 1SS355 * D14 WN672400 DIODE.ZENR P6KE200A 200V D15 VN478200 DIODE D1NL20U D16 VT332900 DIODE 1SS355 D17 VS597600 DIODE.CHP RB160L-40 TE25 D18 VT332900 DIODE 1SS355 D19 VU445900 DIODE RB050L-40 D20 VV463000 DIODE.CHP 1.1A 200V D1FL20U D21 V6267600 DIODE RB051L-40 D22-23 VV463000 DIODE.CHP 1.1A 200V D1FL20U D25 VV463000 DIODE.CHP 1.1A 200V D1FL20U * D27 WR189300 DIODE SG20LC20USM 20.0A D28 VU999500 DIODE.ZENR MAZ8270GML 27.0V D29 VU990500 DIODE.ZENR MAZ8030GLL 2.9V D30 VT332900 DIODE 1SS355 D31-32 V6267600 DIODE RB051L-40 P.C.B. MAIN ✻ New Parts ✻ New Parts YMC-700 YMC-500 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com YMC-700/YMC-500 97 Ref No. Part No. Description Markets Ref No. Part No. Description Markets Value 1/4W Type Part No. 1/6W Type Part No. 11 kΩ HF45 7110 HF45 7110 12 kΩ HJ35 7120 HF85 7120 13 kΩ HF45 7130 HF45 7130 15 kΩ HF45 7150 HF45 7150 18 kΩ HF45 7180 HF45 7180 22 kΩ HF45 7220 HF45 7220 24 kΩ HF45 7240 HF45 7240 27 kΩ HJ35 7270 HF85 7270 30 kΩ HF45 7300 HF45 7300 33 kΩ HF45 7330 HF45 7330 36 kΩ HF45 7360 HF45 7360 39 kΩ HF45 7390 HF45 7390 47 kΩ HF45 7470 HF45 7470 51 kΩ HF45 7510 HF45 7510 56 kΩ HF45 7560 HF45 7560 62 kΩ HF45 7620 HF45 7620 68 kΩ HF45 7680 HF45 7680 82 kΩ HF45 7820 HF45 7820 91 kΩ HF45 7910 HF45 7910 100 kΩ HF45 8100 HF45 8100 110 kΩ HF45 8110 HF45 8110 120 kΩ HF45 8120 HF45 8120 130 kΩ HF45 8130 ✻ 150 kΩ HF45 8150 HF45 8150 180 kΩ HF45 8180 HF45 8180 220 kΩ HJ35 8220 HF85 8220 270 kΩ HF45 8270 HF45 8270 300 kΩ HF45 8300 HF45 8300 330 kΩ HF45 8330 HF45 8330 390 kΩ HJ35 8390 HF85 8390 470 kΩ HF45 8470 HF45 8470 560 kΩ HJ35 8560 HF85 8560 680 kΩ HJ35 8680 HF85 8680 820 kΩ HJ35 8820 HF85 8820 1.0 MΩ HF45 9100 HF45 9100 1.2 MΩ HJ35 9120 ✻ 1.5 MΩ HJ35 9150 HF85 9150 1.8 MΩ HJ35 9180 HF85 9180 2.2 MΩ HJ35 9220 HF85 9220 3.3 MΩ HJ35 9330 HF85 9330 3.9 MΩ HJ35 9390 ✻ 4.7 MΩ HJ35 9470 HF85 9470 10mm HJ35 1/4W Type 5mm HF85 1/6W Type HF45 1/4W Type P.C.B. MAIN P.C.B. WIFI YMC-700 YMC-500 YMC-700 Value 1/4W Type Part No. 1/6W Type Part No. 1.0 Ω HJ35 3100 HF85 3100 1.8 Ω HJ35 3180 ✻ 2.2 Ω HJ35 3220 HF85 3220 3.3 Ω HJ35 3330 HF85 3330 4.7 Ω HJ35 3470 HF85 3470 5.6 Ω HJ35 3560 HF85 3560 10 Ω HF45 4100 HF45 4100 15 Ω HJ35 4150 HF85 4150 22 Ω HF45 4220 HF45 4220 27 Ω HJ35 4270 HF85 4270 33 Ω HF45 4330 HF45 4330 39 Ω HJ35 4470 HF85 4390 47 Ω HF45 4470 HF45 4470 56 Ω HF45 4560 HF45 4560 68 Ω HF45 4680 HF45 4680 75 Ω HF45 4750 HF45 4750 82 Ω HF45 4820 HF45 4820 91 Ω HF45 4910 HF45 4910 100 Ω HF45 5100 HF45 5100 110 Ω HJ35 5110 HF85 5110 120 Ω HF45 5120 HF45 5120 150 Ω HF45 5150 HF45 5150 160 Ω HJ35 5160 ✻ 180 Ω HF45 5180 HF45 5180 200 Ω HF45 5200 HF45 5200 220 Ω HF45 5220 HF45 5220 270 Ω HF45 5270 HF45 5270 330 Ω HF45 5330 HF45 5330 390 Ω HF45 5390 HF45 5390 430 Ω HF45 5430 HF45 5430 470 Ω HF45 5470 HF45 5470 510 Ω HF45 5510 HF45 5510 560 Ω HF45 5560 HF45 5560 680 Ω HF45 5680 HF45 5680 820 Ω HF45 5820 HF45 5820 910 Ω HF45 5910 HF45 5910 1.0 kΩ HF45 6100 HF45 6100 1.2 kΩ HF45 6120 HF45 6120 1.5 kΩ HF45 6150 HF45 6150 1.8 kΩ HF45 6180 HF45 6180 2.0 kΩ HJ35 6200 HF85 6200 2.2 kΩ HF45 6220 HF45 6220 2.4 kΩ HJ35 6240 HF85 6240 2.7 kΩ HF45 6270 HF45 6270 3.0 kΩ HF45 6300 HF45 6300 3.3 kΩ HF45 6330 HF45 6330 3.6 kΩ HJ35 6360 HF85 6360 3.9 kΩ HF45 6390 HF45 6390 4.7 kΩ HF45 6470 HF45 6470 5.1 kΩ HF45 6510 HF45 6510 5.6 kΩ HF45 6560 HF45 6560 6.8 kΩ HF45 6680 HF45 6680 8.2 kΩ HF45 6820 HF45 6820 9.1 kΩ HF45 6910 HF45 6910 10 kΩ HF45 7100 HF45 7100 Carbon Resistors ❊ : Not available D33-35 VT332900 DIODE 1SS355 D1000 VU995700 DIODE.ZENR MAZ8110GLL 10.7V D1001-1004 WB081800 DIODE.SHOT SB01-05Q D2503 VT332900 DIODE 1SS355 ⚠ F1 WB221100 FUSE 5.0A 125V ⚠ * IC1 WP388200 PHOT.CPL TLP781(D4-GR,F) IC2 X7734A00 IC FA5511N-D1-TE1 ⚠ * IC3 WP388200 PHOT.CPL TLP781(D4-GR,F) * IC4 YA712A00 IC TPS54331 DC/DC ⚠ IC5 X8035A00 IC BA00JC5WT-V5 * IC6 X9846A00 IC BD9781HFP IC7 X6770A00 IC NJM431U(TE1) IC8 XJ602A00 IC NJM78M12FA * IC10-11 YA712A00 IC TPS54331 DC/DC IC12 XJ607A00 IC NJM7805FA 5V * IC13 YA576A00 IC LMV431AIMF IC14 XJ604A00 IC NJM78M05FA IC15 XE436A00 IC NJM79M05FA * IC51-53 X9776A00 IC TAS5342LDDV IC54 X7378A00 IC NJM4565M(TE1) IC55 XV190A00 IC NJM2904M OP AMP IC102 X5482A00 IC NE5532DR OP AMP IC103 X7378A00 IC NJM4565M(TE1) IC104 XS790A00 IC TC74HC4052AF MPX IC201 XY879A00 IC TC74HC4053AF(EL) * IC202 YA106A00 IC NJM2580M(TE2) * PJ100 WQ371000 JACK.PIN 4P PJ201 WG471900 JACK.PIN 6P PN50 V9637500 PIN L=70 #18 PN100 V9637500 PIN L=70 #18 ⚠ Q1 VE198800 TR 2SC2705 O,Y Q2 WC435100 TR.DGT KRC104S-RTK Q3 VV556400 TR 2SC2412K Q,R,S ⚠ Q4 WF871900 FET 2SK3523-01R Q5 WC435100 TR.DGT KRC104S-RTK Q11 WC434900 TR.DGT KRA104S-RTK Q12 WC435000 TR.DGT KRC102S-RTK Q500 VR936300 TR 2SA1576A T106 Q501-502 VZ725900 TR 2SD1938F S,T Q1000 VP872700 TR 2SC4488 S,T Q2001-2002 VV556400 TR 2SC2412K Q,R,S R28 WK043700 R.MTL.PLAT 0.012Ω 2W * R45 WF548800 R.WW 0.12Ω 5W * R49-50 VP941300 R.MTL.OXD 2.2KΩ 1W R67-68 VP941100 R.MTL.OXD 1KΩ 1W R70 VP941100 R.MTL.OXD 1KΩ 1W ⚠ RY1 V9366900 RELAY DLS9D1-O(M)0.25W ST251 WA789600 SCR.TERM M3 ⚠ T1 X8521A00 TRANS.PWR ⚠ * T2 X9999A00 TRANS.PWR U AVC-1 ⚠ * TE1 WP173300 INLET.AC INLET AC-008 * TE50 WR056800 TERM.SP 10P MSP-120V2-34 ⚠ TH1 WF875300 POSISTOR NTPAN4R0LDKB0 4.0 WE774300 SCR.BND.HD 3x8 MFZN2W3 * WR117800 P.C.B. WIFI * CB601 WC195200 CN 14P TE * C6003-6005 WP882000 C.CE.CHP 10uF 6.3V C6006-6009 US634100 C.CE.CHP 0.01uF 16V * C6010-6012 WP882000 C.CE.CHP 10uF 6.3V * C6014 WP882000 C.CE.CHP 10uF 6.3V C6015-6016 US035100 C.CE.CHP 0.1uF 16V B C6017 WD758300 C.CE.CHP 10uF 10V D6001 VT332900 DIODE 1SS355 IC602 X8897A00 IC R1172S331B-E2-F * TE601 WE261800 CN.ANT U.FL-R-SMT ✻ New Parts ✻ New Parts w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com A B C D E F G H I J 1 2 3 4 5 6 7 98 YMC-700/YMC-500 • OVERALL ASS'Y YMC-700 YMC-500 52 22 57 54 12 14 13 54 52 55 55 20 54 54 51 52 51 54 51 51 51 58 52 58 52 52 29 56 56 24 15 51 56 56 51 52 35 52 54 50 51 50 54 31 32 (A) 32 (B) 32 (C) 32 (D) 31 23 33 53 59 34 7 8 10 11 5 6 (2) 7 (3) Front panel unit 200-1 200 202 203 204 205 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com A B C D E F G H I J 1 2 3 4 5 6 7 YMC-700/YMC-500 99 * 5 WR117400 P.C.B. ASS'Y MAIN * 6 WR116700 P.C.B. ASS'Y DIGITAL 700 * 6 WR117000 P.C.B. ASS'Y DIGITAL 500 * 7 WR117700 P.C.B. ASS'Y OPERATION * 8 WR117800 P.C.B. ASS'Y WIFI 700 10 WJ559000 FM TUNER FAE381-A08N * 11 WR386600 FLEXIBLE FLAT CABLE 13P 70mm P=1.25 * 12 WR740400 FLEXIBLE FLAT CABLE 17P 80mm P=1 * 13 WR751400 FLEXIBLE FLAT CABLE 27P 80mm P=1 * 14 WR737100 FLEXIBLE FLAT CABLE 14P 80mm P=1 * 15 WR143500 DIPOLE ANTENNA ASS'Y 11B/G BLACK POLE 130mm 700 * 20 WQ700200 SHEET 10x20x0.5 * 22 WQ002900 TOP COVER 700 * 22 WR497800 TOP COVER 500 * 23 WQ003100 SIDE COVER L 700BL * 23 WQ003200 SIDE COVER L 700SI * 23 WR476400 SIDE COVER L 500BL * 23 WR476500 SIDE COVER L 500SI * 24 WQ004100 SIDE COVER R BL * 24 WQ004200 SIDE COVER R SI * 29 WQ002500 REAR PANEL 700 * 29 WQ786400 REAR PANEL 500 31 WH239500 LEG * 32 WQ004600 P.C.B. SUPPORT 700 * 32 WQ770900 P.C.B. SUPPORT 500 * 33 WQ736400 BUTTON TOP * 34 WQ736200 BUTTON TOP CNT ENTER * 35 WQ004800 KNOB D45 BL * 35 WQ004900 KNOB D45 SI 50 VQ368600 PUSH RIVET P3555-B 51 WE774100 BIND HEAD BONDING B-T. SCREW 3x8 MFZN2B3 52 WE774300 BIND HEAD B-TIGHT SCREW 3x8 MFZN2W3 53 WE774800 BIND HEAD P-TIGHT SCREW 3x8 MFZN2W3 54 WF002600 PW HEAD B-TIGHT SCREW 3x8 MFZN2W3 55 WE774600 SCREW IC 3x18 MFZN2W3 56 WE975300 PW HEAD B-TIGHT SCREW 3x8 MFZN2B3 BL 56 VY712800 PW HEAD B-TIGHT SCREW 3x8-8 MFNI33 SI 57 WF266800 FLAT HEAD B-TIGHT SCREW 3x8 MFZN2B3 58 WE877900 BIND HEAD S-TIGHT SCREW 3x6 MFZN2W3 59 WE975300 PW HEAD B-TIGHT SCREW 3x8 MFZN2B3 ACCESSORIES * 200 WQ866700 REMOTE CONTROL RAV35 * 200-1 WS184800 BATTERY COVER CG-26766 * 202 WR143400 IR FLASHER 2P 3m 1pc ⚠ * 203 WR143300 POWER CABLE 2m 1pc 204 WB212500 INDOOR FM ANTENNA 1.4m 1pc 205 WN649600 OPTIMIZER MICROPHONE 6.0m 1pc EM6022L-HN1700 BATTERY R03,AAA,UM-4 2pcs SERVICE TOOLS AAX72980 U.FL REMOVING TOOL U.FL-LP-N-2 CL331-0494-5 WQ662700 FLEXIBLE FLAT CABLE 27P 320mm P=1.0 WQ760200 FLEXIBLE FLAT CABLE 17P 250mm P=1.0 * 1-2 WQ002700 FRONT PANEL 700BL * 1-2 WQ002800 FRONT PANEL 700SI * 1-2 WR159200 FRONT PANEL 500BL * 1-2 WR159300 FRONT PANEL 500SI * 1-4 WQ736500 BUTTON POWER BL * 1-4 WQ736600 BUTTON POWER SI * 1-5 WQ006400 LENS LED BL * 1-5 WQ739400 LENS LED SI * 1-6 WQ006300 LENS IR BL * 1-6 WQ304900 LENS IR SI * 1-7 WQ305100 SUPPORT IR 1-10 WE774800 BIND HEAD P-TIGHT SCREW 3x8 MFZN2W3 1-11 WF268000 BIND HEAD P-TIGHT SCREW 3x10 MFZN2B3 * 7 WR117700 P.C.B. ASS'Y OPERATION • FRONT PANEL UNIT 1-10 1-10 1-10 1-10 1-2 1-4 1-5 1-5 1-6 1-7 7 (5) 7 (1) 7 (4) 1-11 1-11 1-11 1-11 1-11 1-11 1-11 YMC-700 YMC-500 ✻ New Parts ✻ New Parts Ref No. Part No. Description Remarks Markets Ref No. Part No. Description Remarks Markets w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com A B C D E F G H I J 1 2 3 4 5 6 7 100 YMC-700/YMC-500 RAV35 SCHEMATIC DIAGRAM PANEL KEY NO. LAYOUT KEY CODE ■ REMOTE CONTROL Key no. Key name Custom code Data code Operational object 1 POWER 7E 2A YMC 2 TV POWER 7F01 50 TV 3 GUIDE 7F01 60 STB 4 MENU 7F01 5E SOURCE 5 < (up) 7A 9D YMC 6 < (left) 7A 9F YMC 7 ENTER 7A DE YMC 8 > (right) 7A 9E YMC 9 > (down) 7A 9C YMC 10 PREV. (previous) 7F01 5D STB 11 EXIT 7F01 5F SOURCE 12 CONTROL 7A 84 YMC 13 BACK 7A A0 YMC 14 CH < (up) 7F01 0679 STB 15 VOL (volume) + 7A 1A YMC 16 CH > (down) 7F01 027D STB 17 VOL (volume) - 7A 1B YMC 18 PAGE < (up) 7F01 61 STB/YMC 20 PAGE > (down) 7F01 65 STB/YMC 21 MUTE 7A 1C YMC 1 2 3 4 10 18 20 21 14 15 16 17 12 13 11 7 6 8 5 9 U1 uPD6P8AMC-5A4-E1-A 8 9 10 1 2 5 6 7 4 3 13 12 11 20 19 16 15 14 17 18 These PADs are test point for ISP in the production line KI/O6 KI/O7 S0 S1/LED REM VDD XOUT XIN GND S2 KI/O5 KI/O4 KI/O3 KI/O2 KI/O1 KI/O0 KI3 KI2 KI1 KI0 4.00MHz X1 K1 S0 S1 R2 S2 GND VDD 47 ohms C1 47uF R1 1 ohm D1 IR DIODE Q1 VCC 1 3 2 CONTROL CH (up) (up) (down) PAGE (down) CH PAGE VOL.- BACK VOL.+ MUTE GUIDE PREV. EXIT TV POWER POWER MENU ENTER (left) (down) (up) (right) Top view Bottom view w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 101 YMC-700/YMC-500 YMC-700/YMC-500 MEMO www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com YMC-700/YMC-500 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com
