SERVICE MANUAL 1 0 1 0 4 9 IMPORTANT NOTICE This manual has been provided for the use of authorized YAMAHA Retailers and their service personnel. It has been assumed that basic service procedures inherent to the industry, and more specifically YAMAHA Products, are already known and understood by the users, and have therefore not been restated. WARNING: Failure to follow appropriate service and safety procedures when servicing this product may result in personal injury, destruction of expensive components, and failure of the product to perform as specified. For these reasons, we advise all YAMAHA product owners that any service required should be performed by an authorized YAMAHA Retailer or the appointed service representative. IMPORTANT: The presentation or sale of this manual to any individual or firm does not constitute authorization, certification or recognition of any applicable technical capabilities, or establish a principle-agent relationship of any form. The data provided is believed to be accurate and applicable to the unit(s) indicated on the cover. The research, engineering, and service departments of YAMAHA are continually striving to improve YAMAHA products. Modifications are, therefore, inevitable and specifications are subject to change without notice or obligation to retrofit. Should any discrepancy appear to exist, please contact the distributor's Service Division. WARNING: Static discharges can destroy expensive components. Discharge any static electricity your body may have accumulated by grounding yourself to the ground buss in the unit (heavy gauge black wires connect to this buss). IMPORTANT: Turn the unit OFF during disassembly and part replacement. Recheck all work before you apply power to the unit. I CONTENTS TO SERVICE PERSONNEL ...................................... 2–3 PREVENTION OF ELECTROSTATIC DISCHARGE ..... 4 SYSTEM COMPOSITION / システム構成 ..................... 4 FRONT PANEL .............................................................. 5 REMOTE CONTROL PANELS ...................................... 5 REAR PANELS .............................................................. 6 SPECIFICATIONS / 参考仕様 ........................................ 7 INTERNAL VIEW ........................................................... 7 DISASSEMBLY PROCEDURES / 分解手順............ 8–10 TEST MODE / テストモード .................................. 11–12 SERVICE MODE / サービスモード ....................... 13–14 FACTORY MODE / ファクトリーモード............... 13–14 DISPLAY DATA ........................................................... 15 BLOCK DIAGRAM ....................................................... 16 WIRING DIAGRAM ...................................................... 17 PRINTED CIRCUIT BOARDS................................ 18–23 SCHEMATIC DIAGRAMS...................................... 24–27 PIN CONNECTION DIAGRAMS .................................. 28 REPLACEMENT PARTS LIST .............................. 29–32 REMOTE CONTROL.............................................. 32–33 P.O.Box 1, Hamamatsu, Japan CRX-E320/ NX-E700 2007 All rights reserved. This manual is copyrighted by YAMAHA and may not be copied or redistributed either in print or electronically without permission. '07.06 CRX-E320/NX-E700 MICRO COMPONENT SYSTEM MCR-E320 COMPACT DISC RECEIVER/SPEAKER SYSTEM The MCR-E320 consists of the CRX-E320 and the NX-E700. MCR-E320 は CRX-E320 および NX-E700 で構成されています。 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com CRX-E320/NX-E700 2 CRX-E320/ NX-E700 WALL OUTLET EQUIPMENT UNDER TEST AC LEAKAGE TESTER OR EQUIVALENT INSULATING TABLE WARNING: CHEMICAL CONTENT NOTICE! The solder used in the production of this product contains LEAD. In addition, other electrical/electronic and/or plastic (where applicable) components may also contain traces of chemicals found by the California Health and Welfare Agency (and possibly other entities) to cause cancer and/or birth defects or other reproductive harm. DO NOT PLACE SOLDER, ELECTRICAL/ELECTRONIC OR PLASTIC COMPONENTS IN YOUR MOUTH FOR ANY REA- SON WHATSOEVER! Avoid prolonged, unprotected contact between solder and your skin! When soldering, do not inhale solder fumes or expose eyes to solder/flux vapor! If you come in contact with solder or components located inside the enclosure of this product, wash your hands before handling food. 1. Critical Components Information Components having special characteristics are marked s and must be replaced with parts having specifications equal to those originally installed. 2. Leakage Current Measurement (For 120V Models Only) When service has been completed, it is imperative to verify that all exposed conductive surfaces are properly insulated from supply circuits. G Meter impedance should be equivalent to 1500 ohms shunted by 0.15µF. G Leakage current must not exceed 0.5mA. G Be sure to test for leakage with the AC plug in both polarities. 本機に搭載されているすべての基板およびハンダ付けによる接合 部は無鉛ハンダでハンダ付けされています。 無鉛ハンダにはいくつかの種類がありますが、修理時には下記の ような無鉛ハンダの使用を推奨します。 ・Sn+Ag+Cu（錫+銀+銅） ・Sn+Cu（錫+銅） ・Sn+Zn+Bi（錫+亜鉛+ビスマス） 注意： 無鉛ハンダの融点温度は通常の鉛入りハンダに比べ30～40℃ 程度高くなっていますので、それぞれのハンダに合ったハンダ ごてをご使用ください。 All of the P.C.B.s installed in this unit and solder joints are soldered using the lead free solder. Among some types of lead free solder currently available, it is recommended to use one of the following types for the repair work. • Sn + Ag + Cu (tin + silver + copper) • Sn + Cu (tin + copper) • Sn + Zn + Bi (tin + zinc + bismuth) Caution: As the melting point temperature of the lead free solder is about 30°C to 40°C (50°F to 70°F) higher than that of the lead solder, be sure to use a soldering iron suitable to each solder. About lead free solder / 無鉛ハンダについて I TO SERVICE PERSONNEL WARNING: Laser Safety This product contains a laser beam component. This component may emit invisible, as well as visible radiation, which may cause eye damage. To protect your eyes and skin from laser radiation, the following precautions must be used during servicing of the unit. 1) When testing and/or repairing any component within the product, keep your eyes and skin more than 30 cm away from the laser pick-up unit at all times. Do not stare at the laser beam at any time. 2) Do not attempt to readjust, disassemble or repair the laser pick-up, unless noted elsewhere in this manual. 3) CAUTION : Use of controls, adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com CRX-E320/NX-E700 3 CRX-E320/ NX-E700 Laser Emitting conditions: 1) When the top cover is removed, and the STANDBY/ON SW is turned to the “ON” position, the laser component will emit a beam for several seconds to detect if a disc is present. During this time (5-10 sec.) the laser may radiate through the lens of the laser pick-up unit. Do not attempt any servicing during this period! If no disc is detected, the laser will stop emitting the beam. When a disc is loaded, you will not be exposed to any laser emissions. 2) The laser power level can be adjusted with the VR on the pick-up PWB, however, this level has been set by the factory prior to shipping from the factory. Do not adjust this laser level control unless instruction is provided elsewhere in this manual. Adjustment of this control can increase the laser emission level from the device. Laser Diode Properties • Material: GaAlAs • Wavelength: 780 nm • Emission Duration: Continuous • Laser Output: Max. 44.6 µW * * This output is the value measured at a distance of about 200 mm from the objective lens surface on the optical pick-up block. VARO!: AVATTAESSA JA SUOJALUKITUS OHITETTAESSA OLET ALTTIINA NÄKYMÄTTÖMÄLLE LASER- SÄTEILYLLE. ÄLÄ KATSO SÄTEESEEN. VARNING!: OSYNLIG LASERSTRÅLNING NÄR DENNA DEL ÄR ÖPPNAD OCH SPÄRREN ÄR URKOPPLAD. BETRAKTA EJ STRÅLEN. Optical pick-up www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com CRX-E320/NX-E700 4 CRX-E320/ NX-E700 NX-E700 CRX-E320 NX-E700 I SYSTEM COMPOSITION / システム構成 The MCR-E320 consists of the CRX-E320 and the NX-E700. MCR-E320 は CRX-E320 および NX-E700 で構成されています。 Some semiconductor (solid state) devices can be damaged easily by static electricity. Such components commonly are called Electrostatically Sensitive (ES) Devices. Examples of typical ES devices are integrated circuits and some field-effect transis- tors and semiconductor “chip” components. The following techniques should be used to help reduce the incidence of compo- nent damage caused by electrostatic discharge (ESD). 1. Immediately before handling any semiconductor component or semiconductor-equipped assembly, drain off any ESD on your body by touching a known earth ground. Alternatively, obtain and wear a commercially available discharging ESD wrist strap, which should be removed for potential shock reasons prior to applying power to the unit under test. 2. After removing an electrical assembly equipped with ES devices, place the assembly on a conductive surface such as aluminum foil, to prevent electrostatic charge buildup or exposure of the assembly. 3. Use only a grounded-tip soldering iron to solder or unsolder ES devices. 4. Use only an anti-static solder removal device. Some solder removal devices not classified as “anti-static (ESD protected)” can generate electrical charge sufficient to damage ES devices. 5. Do not use freon-propelled chemicals. These can generate electrical charges sufficient to damage ES devices. 6. Do not remove a replacement ES device from its protective package until immediately before you are ready to install it. (Most replacement ES devices are packaged with leads electrically shorted together by conductive foam, aluminum foil or compa- rable conductive material). 7. Immediately before removing the protective material from the leads of a replacement ES divice, touch the protective mate- rial to the chassis or circuit assembly into which the device will be installed. CAUTION: Be sure no power is applied to the chassis or circuit, and observe all other safety precautions. 8. Minimize bodily motions when handling unpackaged replacement ES devices. (Otherwise harmless motion such as the brushing together of your clothes fabric or the lifting of your foot from a carpeted floor can generate static electricity (ESD) sufficient to damage an ES device). Grounding for electrostatic breakdown prevention 1. Human body grounding. Use the anti-static wrist strap to discharge the static electricity from your body. 2. Work table grounding. Put a conductive material (sheet) or steel sheet on the area where the optical pick- up is placed and ground the sheet. Caution: The static electricity of your clothes will not be grounded through the wrist strap. So take care not to let your clothes touch the optical pick-up. 1M-ohms Conductive material (sheet) or steel sheet Anti-static wrist strap I PREVENTION OF ELECTROSTATIC DISCHARGE www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com CRX-E320/NX-E700 7 I INTERNAL VIEW 215 (8-7/16") 308.4 (12-1/8") 15(9/16") 270.4 (10-5/8") 23 (15/16") 113 (4-7/16") 105 (4-1/8") 8 (5/16") I Player Section / プレーヤー部 Playback System / 再生システム .................................................................................. CD, CD-R/RW Audio Performance / オーディオ部性能 (1 kHz) Signal-Noise ............................................................ 100 dB or more Dynamic range ......................................................... 100 dB or more Distortion and Noise ................................................0.005 % or less DAC ........................................................................... 192 kHz/24-bit I Amplifier Section / アンプ部 Minimum RMS Output Power Per Channel / 定格出力 (6-ohm, 1 kHz, 0.5 % THD) .....................................................................................25 W + 25 W Maximum RMS Output Power Per Channel / 実用最大出力 (6-ohm, 1 kHz, 10 % THD) .....................................................................................30 W + 30 W Input Sensitivity/Impedance / 入力感度/インピーダンス AUX etc. ............................................................. 300 mV/47 k-ohms Frequency Response / 周波数特性 (1 W, 6-ohm) CD etc. ..................................................... 20 Hz to 20 kHz ± 0.5 dB Total Harmonic Distortion / 全高調波歪率 (6-ohm, 1 kHz, 1 W) CD etc. .......................................................................0.08 % or less Signal to Noise Ratio / S/N比 (IHF-A network) CD etc. ....................................................................... 95 dB or more Output level/Impedance / 出力レベル/インピーダンス PHONES (Volume max.) ............................................. 1 V/32 ohms I Tuner Section / チューナー部 FM Section / FMチューナー部 Tuning Range / 受信周波数範囲 U, T, K, A, G, L models ................................ 87.50 to 108.00 MHz J model ............................................................ 76.0 to 108.0 MHz Sensitivity / 感度 S/N 30 dB .............................................................7 dBµVm (EMF) AM Section / AMチューナー部 Tuning Range / 受信周波数範囲 U model ............................................................... 530 to 1700 kHz T, K, A, G, L, J models........................................ 522 to 1629 kHz Sensitivity / 感度 S/N 20 dB .................................................................. 60 dB (EMF) I General / 総合 Power Supply / 電源電圧 U model ..................................................................AC 120 V, 60 Hz T, K, A, G, L, J models ......................... AC 100 to 240 V, 50/60 Hz Power Consumption / 消費電力 ................................................................................................. 55 W Standby Power Consumption / 待機時消費電力 .................................................................................... 1.0 W or less Dimensions (W x H x D) / 寸法（幅×高さ×奥行き） ....................... 215 x 113 x 308.4 mm (8-7/16" x 4-7/16" x 12-1/8") Weight / 質量 ......................................................................... 3.1 kg (6 lbs. 13 oz) Finish / 仕上げ Gold color...................................................................... T, A models Black color ................................................................ G, L, J models Silver color ........................................................... U, K, G, L models Accessories / 付属品 Remote control x 1, Indoor FM antenna x 1, AM loop antenna x 1 * Specifications are subject to change without notice due to product improvements. ※ 参考仕様および外観は予告なく変更されることがあります。 I SPECIFICATIONS / 参考仕様 CRX-E320 NX-E700 Type / 型式 ................................. 2-way bass reflex speaker system/ Magnetic shielding type 2ウェイ・バスレス式／防磁型 Driver / スピーカーユニット Woofer ..................................................... 11 cm (4-1/2") cone type Tweeter ........................................................ 2.5 cm (1") dome type Frequency Response / 再生周波数帯域 U, T, K, A, G and L models ..................... 60 Hz to 28 kHz (-10dB) J model .................................................... 60 Hz to 80 kHz (-30dB) Impedance / インピーダンス ................................................. 6 ohms Nominal Input / 許容入力 .......................................................... 40 W Maximum Input / 最大入力 ..................................................... 110 W Sensitivity / 出力音圧レベル .....................................85 dB/2.83 V/m Crossover Frequency / クロスオーバー周波数 .......................3 kHz Input Terminal / 入力端子 .................................. Screw/Banana type Dimensions (W x H x D) / 寸法（幅×高さ×奥行き） ......................................................... 165 mm x 255 mm x 183 mm (6-1/2" x 10-1/16" x 7-3/16") Weight / 質量 .........................................................3.4 kg (7 lbs 8 oz) Finish / 仕上げ .................................................................. Black color Accessories / 付属品 .................................. Speaker cable (4 m) x 2 * Specifications are subject to change without notice due to product improvements. ※ 参考仕様および外観は予告なく変更されることがあります。 • DIMENSIONS / 寸法図 Unit: mm (inch) 単位：mm（インチ） 165(6-1/2") 183(7-3/16") 255(10-1/16") MAIN (1) P.C.B. TUNER MODULE FRONT / SMPS (3) P.C.B. CONNECTOR P.C.B. MAIN (2) P.C.B. FRONT / SMPS (2) P.C.B CD MECHANISM UNIT FRONT / SMPS (1) P.C.B 7 8 1 2 3 4 1 2 3 4 5 6 7 8 5 6 U .......... U.S.A. and Canadian models T .......... Chinese model K .......... Korean model A .......... Australian model G .......... European model L........... Singapore model J ........... Japanese model CRX-E320 NX-E700 CRX-E320 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com CRX-E320/NX-E700 8 Fig. 1 ・ 番号順に部品を取り外してださい。 ・ AC電源コンセントから、電源コードを抜いてください。 1. トップカバーの外し方 a. 1のネジ2本、2のネジ4本を外します。（Fig. 1） b. トップカバーを後方へスライドさせ取り外します。 （Fig. 1） 2. フロントパネルユニットの外し方 a. トレイを開きます。（“手動でトレイを開く方法”を参照） b. トレイリッドを外し、トレイを閉じます。（Fig. 1） c. 3のネジ2本、4のネジ2本を外します。（Fig. 1） d. CN81を外します。（Fig. 1） e. フック2箇所を外し、フロントパネルユニットを前方へ 引き出します。（Fig. 1） f. CN82を外します。（Fig. 1） • Remove parts in disassembly order as numbered. • Disconnect the power cable from the AC outlet. 1. Removal of Top Cover a. Remove 2 screws (1) and 4 screws (2). (Fig. 1) b. Slide the top cover rearward to remove it. (Fig. 1) 2. Removal of Front Panel Unit a. Eject the tray. (See “How to manually eject the tray”.) b. Remove the tray lid and close the tray. (Fig. 1) c. Remove 2 screws (3) and 2 screws (4). (Fig. 1) d. Remove CN81. (Fig. 1) e. Remove 2 hooks and then slide the front panel unit for- ward. (Fig. 1) f. Remove CN82. (Fig. 1) I DISASSEMBLY PROCEDURES / 分解手順 a. Turn the unit bottom up. b. Using a flatblade screwdriver, turn the loading cam 90 degrees in the direction indicated by an arrow in the figure. (Fig. 2) c. Gently pull the tray out. a. 本機を上下反転します。 b. マイナスドライバーでローディングカムを図に示す矢印 の方向に90度回転します。（Fig. 2） c. トレイをそっと引き出します。 • How to manually eject the tray / 手動でトレイを開く方法 Fig. 2 3. FRONT/SMPS（3）P.C.B.の外し方 a. 5のネジ2本を外します。（Fig. 3） b. 6のネジ2本を外します。（Fig. 4） c. CN91、CN92、CN93を外します。（Fig. 3） d. 電源コードを取り外します。（Fig. 3） e. 7のネジ2本を外します。（Fig. 3） f. 8のネジ1本を外します。（Fig. 4） g. FRONT/SMPS（3）P.C.B.をシールドケースと一緒に取 り外します。 （Fig. 3） 4. CDメカユニットの外し方 a. 9のネジ4本を外します。（Fig. 3） b. CN31、CN32を外します。（Fig. 3） c. CDメカユニットを取り外します。（Fig. 3） 5. チューナーモジュールの外し方 a. 0のネジ2本を外します。（Fig. 4） b. CN45を外します。（Fig. 3） c. チューナーモジュールを取り外します。（Fig. 3） 6. MAIN（1）P.C.B.の外し方 a. Aのネジ2本、Bのネジ1本、Cのネジ5本を外しま す。（Fig. 3） b. Dのネジ4本を外します。 （Fig. 4） c. MAIN（1）P.C.B.をヒートシンクと一緒に取り外しま す。（Fig. 3） 3. Removal of FRONT/SMPS (3) P.C.B. a. Remove 2 screws (5). (Fig. 3) b. Remove 2 screws (6). (Fig. 4) c. Remove CN91, CN92 and CN93. (Fig. 3) d. Remove power cable. (Fig. 3) e. Remove 2 screws (7). (Fig. 3) f. Remove screw (8). (Fig. 4) g. Remove FRONT/SMPS (3) P.C.B. together with the shield case. (Fig. 3) 4. Removal of CD Mechanism Unit a. Remove 4 screws (9). (Fig. 3) b. Remove CN31 and CN32. (Fig. 3) c. Remove CD mechanism unit. (Fig. 3) 5. Removal of Tuner Module a. Remove 2 screws (0). (Fig. 4) b. Remove CN45. (Fig. 3) c. Remove tuner module. (Fig. 3) 6. Removal of MAIN (1) P.C.B. a. Remove 2 screws (A), screw (B) and 5 screws (C). (Fig. 3) b. Remove 4 screws (D). (Fig. 4) c. Remove MAIN (1) P.C.B. together with the heat sink. (Fig. 3) 1 1 3 3 2 2 4 Top cover トップカバー� Front panel unit フロントパネルユニット� Tray lid トレイリッド� Hook フック� Hook フック� CN81 CN82 Tray トレイ� Loading cam ローディングカム� Tray トレイ� Flatblade screwdriver マイナスドライバー� Bottom side 底面� CRX-E320 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com CRX-E320/NX-E700 9 CRX-E320/ NX-E700 Fig. 3 Fig. 4 6 6 8 0 D 5 7 9 9 7 A B C C Power cable 電源コード� Tuner module チューナーモジュール� Heat sink ヒートシンク� Shield case シールドケース� CD mechanism unit CDメカユニット� CN91 CN93 CN45 CN31 CN32 CN92 MAIN (1) P.C.B. MAIN (2) P.C.B. FRONT/SMPS (3) P.C.B. CONNECTOR P.C.B. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com CRX-E320/NX-E700 10 CRX-E320/ NX-E700 7. オプティカルピックアップユニットの外し方 a. Eのネジ4本を外し、ドライブユニットを取り外しま す。（Fig. 5） b. カード電線、コネクターASSYを外します。 （Fig. 5） c. ギアAストッパーを外し、ギアAを取り外します。（Fig. 6） d. スレッドシャフトストッパーを外し、スレッドシャフ トを取り外します。（Fig. 6） e. オプティカルピックアップユニットを取り外します。 （Fig. 6） * オプティカルピックアップユニットに搭載されてい る可変抵抗（VR301）は、絶対に触らないでくださ い。（Fig. 7） 7. Removal of Optical Pick-up Unit a. Remove 4 screws (E) and then remove the drive unit. (Fig. 5) b. Remove flexible flat cable and connector ass’y. (Fig. 5) c. Remove stopper gear A and then remove the gear A. (Fig. 6) d. Remove stopper sled shaft and then remove the sled shaft. (Fig. 6) e. Remove the optical pick-up unit. (Fig. 6) * Never touch the potentiometer (VR301) installed to the optical pick-up unit. (Fig. 7) Fig. 5 Fig. 7 Fig. 6 E E CD mechanism unit CDメカユニット� Drive unit ドライブユニット� Flexible flat cable カード電線� Connector ass'y コネクターASSY Optical pick-up unit オプティカルピックアップユニット� Sled shaft スレッドシャフト� Stopper sled shaft スレッドシャフトストッパー� Stopper gear A ギアAストッパー� Gear A ギアA Optical pick-up unit オプティカルピックアップユニット� Potentiometer 可変抵抗� www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com CRX-E320/NX-E700 11 CRX-E320/ NX-E700 FFFFF (OPEN/CLOSE) W WW WW / DDDDD (PLAY/PAUSE) A AA AA (STOP) T T T T T / E E E E E (SKIP-/SEARCH-) R R R R R / Y Y Y Y Y (SKIP+/SEARCH+) FFFFF (OPEN/CLOSE) W WW WW (PLAY) DDDDD (PAUSE) A AA AA (STOP) T T T T T (SKIP-) Y Y Y Y Y (SKIP+) TIME/INFO RANDOM Panel key Panel key • Function list of remote control keys. • Function list of panel keys. *1 Check FIP display The display condition varies as shown below accord- ing to the “TIME/INFO” key of the remote control. I TEST MODE Operation and FIP display of the CD mechanism unit are checked. • Starting Test Mode a. Connect the power cable to the AC power outlet. b. Press the “STANDBY/ON” key while simultaneously pressing “W WW WW / DDDDD” (PLAY/PAUSE) and “A AA AA” (STOP) keys of the main unit. c. TEST mode is activated and “TEST MODE” flashes for about 2 seconds. d. When using the input source other than [CD] for the main unit, press the “CD” key of the remote control to set the input source as [CD]. * While the TEST mode is at work, it is not possible to change the input source even by pressing the “INPUT” key of the main unit. • Canceling Test Mode Press the “STANDBY/ON” key of the main unit and disconnect the power cable from the AC power outlet. Starting TEST mode 2 seconds While the TEST mode is activated, the indicator remains ON constantly. Tray open/close. Playback/Pause. Stop. Move traverse reverse. Move traverse forward. Tray open/close. Playback. Pause. Stop. Move traverse reverse. Move traverse forward. Check FIP display. (*1) Spindle servo on/off. Function Function Initial display Segments off Icon (right) Pattern 1 Pattern 2 Pattern 3 Pattern 4 Pattern 5 Pattern 6 Pattern 7 (Indicator remains ON constantly.) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com CRX-E320/NX-E700 12 CRX-E320/ NX-E700 ・ リモコンキー操作リスト FFFFF （OPEN/CLOSE） W WW WW / DDDDD （PLAY/PAUSE） A AA AA （STOP） T T T T T / E E E E E （SKIP-/SEARCH-） R R R R R / Y Y Y Y Y （SKIP+/SEARCH+） トレイ オープン／クローズ 再生／一時停止 停止 トラバース内周移動 トラバース外周移動 パネルキー 機能 ・ パネルキー操作リスト FFFFF （OPEN/CLOSE） W WW WW （PLAY） DDDDD （PAUSE） A AA AA （STOP） T T T T T （SKIP-） Y Y Y Y Y （SKIP+） TIME/INFO RANDOM トレイ オープン・クローズ 再生 一時停止 停止 トラバース内周移動 トラバース外周移動 表示器チェック（*1） スピンドルサーボオン／オフ パネルキー 機能 *1 表示器のチェック リモコンの“TIME/INFO”キーを押すことにより、表 示状態が下記のように変わります。 I テストモード CDメカユニットの動作チェックおよび表示器のチェックを行います。 ・ テストモードの起動 a. 電源コードをACコンセントに接続します。 b. 同時に本機の“W WW WW / DDDDD” （PLAY/PAUSE）キーと“A AA AA” （STOP）キーを押しながら、“STANDBY/ON”キーを押します。 c. テストモードが起動し、約2秒間“TEST MODE”が点滅表示されます。 d. 本機の入力ソースが「CD｣以外の場合、リモコンの“CD”キーを押して本機の入力ソースを「CD」に設定します。 ＊ テストモード起動中、本機の“INPUT”キーを押しても入力ソースは変更できません。 初期表示� 表示オフ� （インジケーターは常時点灯）� モード� パターン1 パターン2 パターン3 パターン4 パターン5 パターン6 パターン7 テストモード起動� 2秒後� テストモード起動中、インジケーターは常時点灯します。� ・ テストモードの解除 本機の“STANDBY/ON”キーを押し、ACコンセントから電源コードを抜きます。 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com CRX-E320/NX-E700 13 CRX-E320/ NX-E700 I SERVICE MODE The firmware versions of the main microprocessor, DSP and USB microprocessors are displayed. • Starting Service Mode a. Connect the power cable to the AC power outlet. b. To open the tray, press the “F”(EJECT) key of the main unit or “OPEN/CLOSE” key of the remote control. c. With the tray drawn out, press and hold the “A” (STOP) key of the main unit for about 4 seconds. Then the SERVICE mode is activated. Each firmware version is displayed at about 5 seconds intervals. d. To close the tray, press the “F”(EJECT) key of the main unit or “OPEN/CLOSE” key of the remote control. e. Press the “STANDBY/ON” key of the main unit or “STANDBY/ON” key of the remote control and disconnect the power cable from the AC power outlet. I FACTORY MODE Factory settings are restored and the tuner step is changed (L model). • Starting Factory Reset All settings are returned to initial settings. a. Connect the power cable to the AC power outlet. b. Press the “STANDBY/ON” key for about 4 seconds continuously while pressing “SOUND” and “MODE” keys of the main unit simultaneously. [FACTORY RESET] is displayed and after about 4 seconds, the power is turned off automatically. c. Disconnect the power cable from the AC power outlet. • Starting Tuner Step (L model) Select the tuner step AM9kHz/FM50kHz or AM10kHz/FM100kHz. The initial setting becomes AM9kHz/FM50kHz. a. Connect the power cable to the AC power outlet. b. Press the “STANDBY/ON” key for about 4 seconds continuously while pressing “SOUND” and “INPUT” keys of the main unit simultaneously, [10kHz/100kHz] flashes and after about 4 seconds, the power is turned off automatically. * The setting is changed to [9kHz/50kHz] when the tuner step is activated again. Destination indication About 5 seconds About 5 seconds About 5 seconds Normal display The firmware version of the main microprocessor is displayed. The firmware version of DSP is displayed. The firmware version of the USB microprocessor is displayed. This is displayed when the SERVICE mode is activated. (Default) This setting change takes place every time the tuner step is activated. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com CRX-E320/NX-E700 14 CRX-E320/ NX-E700 I サービスモード メインマイコン、DSP、USBマイコンのファームウェアバージョンを表示します。 ・ サービスモードの起動 a. 電源コードをACコンセントに接続します。 b. 本機の“FFFFF” （イジェクト）キーまたはリモコンの“OPEN/CLOSE”キーを押し、トレイを引き出します。 c. トレイを引き出した状態で、本機の“A AA AA” （STOP）キーを約4秒間押し続けます。 サービスモードが起動します。 各ファームウェアバージョンは約5秒間隔で表示されます。 サービスモード起動時、表示されます。� メインマイコンのファームウェアバージョンが表示されます。� 仕向け表示� DSPのファームウェアバージョンが表示されます。� USBマイコンのファームウェアバージョンが表示されます。� 通常表示� 約5秒間� 約5秒間� 約5秒間� d. 本機の“FFFFF” （イジェクト）キーまたは、リモコンの“OPEN/CLOSE”キーを押し、トレイを閉じます。 e. 本機の“STANDBY/ON”キーまたはリモコンの“STANDBY/ON”キーを押し、ACコンセントから電源コードを抜きま す。 I ファクトリーモード ・ ファクトリーリセットの起動 すべての設定を初期設定に戻します。 a. 電源コードをACコンセントに接続します。 b. 同時に本機の“SOUND”キーと“MODE”キーを押しながら、“STANDBY/ON”キーを約4秒間押し続けます。 「FACTORY RESET」が表示され、約4秒後自動で電源オフされます。 c. ACコンセントから電源コードを抜きます。 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com CRX-E320/NX-E700 15 I DISPLAY DATA Note : 1) F+, F- ..... Filament pin 2) DO ..... Serial data output 3) Test ..... Be left open if not used. 4) NP ..... No pin Pin No. Connection 1 F+ 2 F+ 3 NP NP NP NP NP NP NP NP NP NP NP NP NP NP NP NP NP NP NP NP NP NP NP NP NP NP NP NP NP NP NP NP NP NP NP NP NP 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 Pin No. Connection 28 29 30 31 32 33 34 35 36 37 38 39 40 Test 41 DO 42 DA 43 /CP 44 /CS 45 /RST 46 OSCO 47 VDD 48 D-GND 49 L-GND 50 VDISP 51 NP 52 NP 53 F- 54 F- G FIP1: HCA-17SM03T (FRONT/SMPS P.C.B.) G PIN CONNECTION G GRID ASSIGNMENT 1G 1 2G 3G 4G 5G 6G 7G 8G 9G 10G 11G 12G 13G 14G 15G 16G 17G 1G 1G PATTERN AREA n 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60 61 62 63 64 65 66 67 (2G~17G) 68 69 70 G ANODE CONNECTION COM2 – COM3 COM15 COM16 COM17 COM1 1G 2G – 3G 15G 16G 17G SEGB1 SEGB2 SEGB3 SEGB4 SEGB5 SEGB6 SEGB7 SEGB8 SEGB9 SEGB10 10 10 10 10 10 10 SEGB11 11 9 11 11 11 11 11 SEGB12 12 12 12 12 12 12 SEGB13 13 13 13 13 13 13 SEGB14 14 14 14 14 14 14 SEGB15 15 15 15 15 15 15 SEGB16 16 16 16 16 16 16 SEGB17 17 17 17 17 17 17 SEGB18 18 1 1 1 1 1 1 2 2 2 2 2 2 3 3 3 3 3 3 4 5 6 7 8 9 4 5 6 7 8 9 4 5 6 7 8 9 4 5 6 7 8 9 4 5 6 7 8 9 4 5 6 7 8 18 18 18 18 18 SEGB19 19 19 19 19 19 19 SEGB20 20 20 20 20 20 20 SEGB21 21 21 21 21 21 21 SEGB22 22 22 22 22 22 22 SEGB23 23 23 23 23 23 23 SEGB24 24 24 24 24 24 24 SEGB25 25 25 25 25 25 25 SEGB26 26 26 26 26 26 26 SEGB27 27 27 27 27 27 27 SEGB28 28 28 28 28 28 28 SEGB29 29 29 29 29 29 29 SEGB30 30 30 30 30 30 30 SEGB31 31 31 31 31 31 31 SEGB32 32 32 32 32 32 32 SEGB33 33 33 33 33 33 33 SEGB34 34 34 34 34 34 34 SEGB35 35 35 35 35 35 35 COM1 COM2 – COM3 COM15 COM16 COM17 1G 2G – 3G 15G 16G 17G SEGA1 36 36 36 36 36 36 SEGA2 37 37 37 37 37 37 SEGA3 38 38 38 38 38 38 SEGA4 39 39 39 39 39 39 SEGA5 40 40 40 40 40 40 SEGA6 41 41 41 41 41 41 SEGA7 42 42 42 42 42 42 SEGA8 43 43 43 43 43 43 SEGA9 44 44 44 44 44 44 SEGA10 45 45 45 45 45 45 SEGA11 46 46 46 46 46 46 SEGA12 47 47 47 47 47 47 SEGA13 48 48 48 48 48 48 SEGA14 49 49 49 49 49 49 SEGA15 50 50 50 50 50 50 SEGA16 51 51 51 51 51 51 SEGA17 52 52 52 52 52 52 SEGA18 53 53 53 53 53 53 SEGA19 54 54 54 54 54 54 SEGA20 55 55 55 55 55 55 SEGA21 56 56 56 56 56 56 SEGA22 57 57 57 57 57 57 SEGA23 58 58 58 58 58 58 SEGA24 59 59 59 59 59 59 SEGA25 60 60 60 60 60 60 SEGA26 61 61 61 61 61 61 SEGA27 62 62 62 62 62 62 SEGA28 63 63 63 63 63 63 SEGA29 64 64 64 64 64 64 SEGA30 65 65 65 65 65 65 SEGA31 66 66 66 66 66 66 SEGA32 67 67 67 67 67 67 SEGA33 68 68 68 68 68 68 SEGA34 69 69 69 69 69 69 SEGA35 70 70 70 70 70 70 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 2 A B C D E F G H I J 1 3 4 5 7 CRX-E320/NX-E700 6 16 I BLOCK DIAGRAM MAIN • See page 24 → SCHEMATIC DIAGRAM FRONT/SMPS • See page 25-26 → SCHEMATIC DIAGRAM FRONT/SMPS • See page 25-26 → SCHEMATIC DIAGRAM +3.3V 2,14,23 +8VM +3.3V +VREF FOO 9 +1.5V FOCUS+/- TRO +VREF TRACK+/- FMO SLED+/- DMD SPINDLE+/- LD LD PD A-E LOADING+/- POWER-H X301 16.934MHz 62 63,64 61 +12V +12V USB+5V RMCK DIGITAL-OUT DIGITAL OUT ANALOG-OUT (CD/USB) OPTICAL L+/-,R+/- JK21 BCK/LRCK 67 61,65 58,59 -12V VDD AK_CS/RESET +35V X201 32.768kHz Pull-up 10 k-ohms X202 20MHz FL+/FL- 17-21 CLK/DATA DATA/CLK REMOTE TU-L/R VOLUME +/- JOG +/- +3.3V X401 9MHz KEY0-2 D+/D- USBDP/USBDM JK83 79,80 USB_PON HP-ON SP-ON F_MUTE 7 CD/USB L/R +12V +12V 2 JK81 +22VA +12V TUNER L/R 5,24 SPEAKERS FL-OUT 5 7 PRE-LCH FL-CH 5 AUX3 L/R JK82 AUX L/R 9,20 FR-OUT 3 PRE-RCH FR-CH 6 1 JK22 JK23 -12V AUX_O L/R 12,17 7,16 -22VA SW SUBWOOFER JK22 JK24 13 10 69 25 24 18 1 11 5 FL-ON 82 13 12 1,3 32 12 10 31 13 94-98,100 9 10 12 2,4 3 23 24 1 9-12 14 CD-LIMIT-SW CD-OPEN-M/CD-CLOSE-M CD-OPEN-SW/CD-CLOSE-SW 4,25 71-74 2,27 2,3,5,6 7,22 10,19 OUT L/R REC L/R 10,14 3,26 AC_IN USB+5V FL-ON PROTECT -12V HP-ON +12V L ch R ch 3 4 OUT 6K8 OPEN HP-IN 95,96 97,98 35 U5V U5V +35V FL+/FL- 15,16 17,18 19,20 21,22 PULL-UP5V V-PROTECT +3.3V 34,35 28 2 RESET 30 5 4 SPK-ON 5-8 14 +22VA -22VA +12V -12V +8VM PWE-MUTE ST5.6V PWR-ON PHONES 91 +3.3V USB+5V 5 43 USB+5V 4 1 100 73 75 PORTABLE IN AUX U J L G A K T PROTECT (MAIN-AMP) V-PROTECT (VOLTAGE) 4K3 2K4 10 R242 1K 10K 15K OUT L/R FM ANT. AM ANT. USB IN L/R 99 DEST. TUNER MODULE CD MECHANISM UNIT KSL-2130CCMZ IC29 MOTOR DRIVE TA2125 IC28 DAC AK4385 IC30 L.P.F. IC21 USB DECODER TMP92CD28FG IC24 MICROPROCESSOR T5CD2 FIP1 FIP DISPLAY HCA-17SM03T IC32 INPUT SELECTOR TC9163CFG Q503-508 MUTING IC33 VOLUME CONTROL TDA7313 IC31 PRE- AMP NJM2068 (+6 dB) Q518-519 IC27 CD DRIVER / DSP TC94A70FG Q301 LD IC34 IC25 MAIN-AMP STK4142 (+18 dB) RY51 SPEAKER RELAY L.P.F. SMPS IC35 +5V IC26 +1.5V Q201,202 IC20 RY50 PHONES RELAY Q522 IC22 LIMIT IC Q513-517,520,521 PROTECTION IC27 CD DRIVER / DSP R242 VR81 VOLUME VR82 MULTI JOG /ENTER KEY SW81-88 PANEL KEYS RC81 SENSOR w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com A B C D E F G H I J 1 2 3 4 5 6 7 CRX-E320/NX-E700 17 I WIRING DIAGRAM CD MECHANISM UNIT USB CD MECHANISM UNIT (POSITION) FRONT/ SMPS (2) P.C.B. MAIN (1) P.C.B. MAIN (2) P.C.B. AC IN FRONT/SMPS (1) P.C.B. FRONT/SMPS (3) P.C.B. CONNECTOR P.C.B. TUNER MODULE 5P 11P, 80mm 21P, 180mm 6P 13P 11P 13P 11P 16P, 150mm BN83 CN85 CN92 BN82 CN45 CN31 BN93 CN83 CN50 CN91 BN50 CN96A CN96B CN98B CN98A CN98D BN92 CN93 Power supply CN98C CN97B CN97A CN82 CN81 CN81 CN84 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 2 A B C D E F G H I J 1 3 4 5 7 CRX-E320/NX-E700 6 18 I PRINTED CIRCUIT BOARDS FOR INFORMATION ONLY (COMPONENT PARTS NOT AVAILABLE) FRONT/SMPS (1) (CN81) FRONT/SMPS (1) (BN82) FRONT/SMPS (3) (BN92) FRONT/SMPS (3) (CN93) FRONT/SMPS (2) (BN83) CD MECHANISM UNIT TUNER (Top view) MAIN (1) P.C.B. MAIN (2) P.C.B. (Top view) ( ) Writing port Microprocessor ( ) Writing port USB 1 2 3 4 8 7 6 5 SUBWOOFER OUT AUX DIGITAL OPTICAL OUT SPEAKERS OUT L/R IN L/R L + / - R + / - Note) The electrical parts available as servicing parts are those in the replacement parts list only. When replacement of any electrical part other than those in the list is necessary, replace the P.C.B. assembly which includes that part. 注） 電気部品リストに記載されている電気部品のみ、サービス部品として供給できます。 電気部品リストに記載されていない電気部品の交換が必要な場合は、その電気部品を搭載している「P.C.B. ASSY」を交換 してください。 CRX-E320 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com A B C D E F G H I J 1 2 3 4 5 6 7 CRX-E320/NX-E700 19 MAIN (1) P.C.B. MAIN (2) P.C.B. (Bottom view) (Bottom view) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 2 A B C D E F G H I J 1 3 4 5 7 CRX-E320/NX-E700 6 20 MAIN (1) (CN83) CD MECHANISM UNIT MAIN (1) (CN81) MAIN (1) (CN82) STANDBY /ON SOUND MODE TIMER STOP PLAY PAUSE INPUT VOLUME MULTI JOG PHONES PORTABLE USB OPEN /CLOSE (Top view) FRONT/SMPS (1) P.C.B. (Top view) FRONT/SMPS (2) P.C.B. w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com A B C D E F G H I J 1 2 3 4 5 6 7 CRX-E320/NX-E700 21 (Bottom view) FRONT/SMPS (1) P.C.B. (Bottom view) FRONT/SMPS (2) P.C.B. w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 2 A B C D E F G H I J 1 3 4 5 7 CRX-E320/NX-E700 6 22 Safety Measures • Some internal parts in this product contain high voltages and are dangerous. Be sure to take safety measures during servicing, such as wearing insulating gloves. • C901 on the FRONT/SMPS (3) P.C.B. are dangerous, for a high voltage is retained there even after the power is turned off. Before the repair work, connect a resistor about 5 k-ohms/10 W between terminals of the capacitor to force discharge. After the repair work, also perform force discharge by connecting a resistor about 5 k-ohms/10 W between terminals of the capacitor. 安全対策� ・ この製品の内部には高電圧部分があり危険です。修理の際は、絶縁性の手袋を使用するなどの安全対策を行ってくだ さい。� ・ FRONT/SMPS（3）P.C.B.のC901には電源OFF後も高電圧が維持されるため危険です。� 修理前に5 kΩ/10 W程度の抵抗をコンデンサの端子間に接続して強制放電してください。� また、修理後も同様に5 kΩ/10 W程度の抵抗をコンデンサの端子間に接続して強制放電してください。� AC IN (Top view) FRONT/SMPS (3) P.C.B. CONNECTOR P.C.B. (Top view) MAIN (1) (BN93) MAIN (1) (CN92) 5 k-ohms 10W w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com A B C D E F G H I J 1 2 3 4 5 6 7 CRX-E320/NX-E700 23 (Bottom view) FRONT/SMPS (3) P.C.B. w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 2 A B C D E F G H I J 1 3 4 5 7 CRX-E320/NX-E700 6 24 I SCHEMATIC DIAGRAMS MAIN SUBWOOFER OUT CD MECHANISM UNIT L R L R L R SPEAKERS ( ) Writing port Microprocessor ( ) Writing port USB DIGITAL OPTICAL OUT AUX To TUNER IN OUT to FRONT/SMPS (3)_BN92 Page 26 I5 to FRONT/SMPS (1)_CN81 Page 25 B3 to FRONT/SMPS (1)_BN82 Page 25 E7 to FRONT/SMPS (3)_CN93 Page 26 I3 to FRONT/SMPS (2)_BN83 Page 25 H2 MAIN AMP MAIN (1) MAIN (2) CD DRIVER/DSP USB DECODER (CD=MASK) (FD=FLASH) MICROPROCESSOR INPUT SELECTOR PRE AMP VOLUME CONTROL DAC L.P.F. MOTOR DRIVE Note) The electrical parts available as servicing parts are those in the replacement parts list only. When replacement of any electrical part other than those in the list is necessary, replace the P.C.B. assembly which includes that part. 注） 電気部品リストに記載されている電気部品のみ、サービス部品として供給できます。 電気部品リストに記載されていない電気部品の交換が必要な場合は、その電気部品を搭載している「P.C.B. ASSY」を交換 してください。 CRX-E320 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com A B C D E F G H I J 1 2 3 4 5 6 7 CRX-E320/NX-E700 25 FRONT/SMPS 1/2 PORTABLE USB CD MECHANISM UNIT PHONES to MAIN (1)_CN81 Page 24 B3 to MAIN (1)_CN82 Page 24 G2 to MAIN (1)_CN83 Page 24 I2 FRONT/SMPS (1) FRONT/SMPS (2) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 2 A B C D E F G H I J 1 3 4 5 7 CRX-E320/NX-E700 6 26 AC IN 5 k-ohms 10W Safety Measures • Some internal parts in this product contain high voltages and are dangerous. Be sure to take safety measures during servicing, such as wearing insulating gloves. • C901 on the FRONT/SMPS (3) P.C.B. are dangerous, for a high voltage is retained there even after the power is turned off. Before the repair work, connect a resistor about 5 k-ohms/10 W between terminals of the capacitor to force discharge. After the repair work, also perform force discharge by connecting a resistor about 5 k-ohms/10 W between terminals of the capacitor. 安全対策� ・ この製品の内部には高電圧部分があり危険です。修理の際は、絶縁性の手袋を使用するなどの安全対策を行っ てください。� ・ FRONT/SMPS（3）P.C.B.のC901には電源OFF後も高電圧が維持されるため危険です。� 修理前に5 kΩ/10 W程度の抵抗をコンデンサの端子間に接続して強制放電してください。� また、修理後も同様に5 kΩ/10 W程度の抵抗をコンデンサの端子間に接続して強制放電してください。� to MAIN (1)_CN92 Page 24 B4 to CONNECTOR_CN96B Page 27 C4 to CONNECTOR_CN98C Page 27 H2 to CONNECTOR_CN98B Page 27 H4 to CONNECTOR_CN97B Page 27 C2 to MAIN (1)_BN93 Page 24 I6 FRONT/SMPS (3) FOR INFORMATION ONLY (NO COMPONENT PARTS NOT AVAILABLE) FRONT/SMPS 2/2 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com A B C D E F G H I J 1 2 3 4 5 6 7 CRX-E320/NX-E700 27 to FRONT/SMPS (3)_CN96A Page 26 D6 to FRONT/SMPS (3)_CN97A Page 26 B5 to FRONT/SMPS (3)_CN98D Page 26 F5 to FRONT/SMPS (3)_CN98A Page 26 G6 CONNECTOR CONNECTOR w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com CRX-E320/NX-E700 28 I PIN CONNECTION DIAGRAMS • ICs 28 14 1 16 8 1 1 18 36 18 1 28 14 1 50 75 76 1 51 25 26 100 AK4385ET STK4142MK2 TA2125AFG TDA7313NDTR TMP92CD28FG TC9163CFG w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com CRX-E320/NX-E700 29 I REPLACEMENT PARTS LIST ABBREVIATIONS IN THIS LIST ARE AS FOLLOWS: C.A.EL.CHP : CHIP ALUMI.ELECTROLYTIC CAP C.CE : CERAMIC CAP C.CE.ARRAY : CERAMIC CAP ARRAY C.CE.CHP : CHIP CERAMIC CAP C.CE.ML : MULTILAYER CERAMIC CAP C.CE.M.CHP : CHIP MULTILAYER CERAMIC CAP C.CE.SAFTY : RECOGNIZED CERAMIC CAP C.CE.TUBLR : CERAMIC TUBULAR CAP C.CE.SMI : SEMI CONDUCTIVE CERAMIC CAP C.EL : ELECTROLYTIC CAP C.MICA : MICA CAP C.ML.FLM : MULTILAYER FILM CAP C.MP : METALLIZED PAPER CAP C.MYLAR : MYLAR FILM CAP C.MYLAR.ML : MULTILAYER MYLAR FILM CAP C.PAPER : PAPER CAPACITOR C.PLS : POLYSTYRENE FILM CAP C.POL : POLYESTER FILM CAP C.POLY : POLYETHYLENE FILM CAP C.PP : POLYPROPYLENE FILM CAP C.TNTL : TANTALUM CAP C.TNTL.CHP : CHIP TANTALUM CAP C.TRIM : TRIMMER CAP CN : CONNECTOR CN.BS.PIN : CONNECTOR,BASE PIN CN.CANNON : CONNECTOR,CANNON CN.DIN : CONNECTOR,DIN CN.FLAT : CONNECTOR,FLAT CABLE CN.POST : CONNECTOR,BASE POST COIL.MX.AM : COIL,AM MIX COIL.AT.FM : COIL,FM ANTENNA COIL.DT.FM : COIL,FM DETECT COIL.MX.FM : COIL,FM MIX COIL,OUTPT : OUTPUT COIL DIOD.ARRAY : DIODE ARRAY DIODE.BRG : DIODE BRIDGE DIODE.CHP : CHIP DIODE DIODE.VAR : VARACTOR DIODE DIOD.Z.CHP : CHIP ZENER DIODE DIODE.ZENR : ZENER DIODE DSCR.CE : CERAMIC DISCRIMINATOR FER.BEAD : FERRITE BEADS FER.CORE : FERRITE CORE FET.CHP : CHIP FET FL.DSPLY : FLUORESCENT DISPLAY FLTR.CE : CERAMIC FILTER FLTR.COMB : COMB FILTER MODULE FLTR.LC.RF : LC FILTER,EMI GND.MTL : GROUND PLATE GND.TERM : GROUND TERMINAL HOLDER.FUS : FUSE HOLDER IC.PRTCT : IC PROTECTOR JUMPER.CN : JUMPER CONNECTOR JUMPER.TST : JUMPER,TEST POINT L.DTCT : LIGHT DETECTING MODULE L.EMIT : LIGHT EMITTING MODULE LED.DSPLY : LED DISPLAY LED.INFRD : LED,INFRARED MODUL.RF : MODULATOR,RF PHOT.CPL : PHOTO COUPLER PHOT.INTR : PHOTO INTERRUPTER PHOT.RFLCT : PHOTO REFLECTOR PIN.TEST : PIN,TEST POINT PLST.RIVET : PLASTIC RIVET R.ARRAY : RESISTOR ARRAY R.CAR. : CARBON RESISTOR R.CAR.CHP : CHIP RESISTOR R.CAR.FP : FLAME PROOF CARBON RESISTOR R.FUS : FUSABLE RESISTOR R.MTL.CHP : CHIP METAL FILM RESISTOR R.MTL.FLM : METAL FILM RESISTOR R.MTL.OXD : METAL OXIDE FILM RESISTOR R.MTL.PLAT : METAL PLATE RESISTOR RSNR.CE : CERAMIC RESONATOR RSNR.CRYS : CRYSTAL RESONATOR R.TW.CEM : TWIN CEMENT FIXED RESISTOR R.CEMENT : CEMENT RESISTOR SCR.BND.HD : BIND HEAD B-TIGHT SCREW SCR.BW.HD : BW HEAD TAPPING SCREW SCR.CUP : CUP TIGHT SCREW SCR.TERM : SCREW TERMINAL SCR.TR : SCREW,TRANSISTOR SUPRT.PCB : SUPPORT,P.C.B. SURG.PRTCT : SURGE PROTECTOR SW.TACT : TACT SWITCH SW.LEAF : LEAF SWITCH SW.LEVER : LEVER SWITCH SW.MICRO : MICRO SWITCH SW.PUSH : PUSH SWITCH SW.RT.ENC : ROTARY ENCODER SW.RT.MTR : ROTARY SWITCH WITH MOTOR SW.RT : ROTARY SWITCH SW.SLIDE : SLIDE SWITCH TERM.SP : SPEAKER TERMINAL TERM.WRAP : WRAPPING TERMINAL THRMST.CHP : CHIP THERMISTOR TR.CHP : CHIP TRANSISTOR TR.DGT : DIGITAL TRANSISTOR TR.DGT.CHP : CHIP DIGITAL TRANSISTOR TRANS : TRANSFORMER TRANS.PULS : PULSE TRANSFORMER TRANS.PWR : POWER TRANSFORMER ASS’Y TUNER.AM : TUNER PACK,AM TUNER.FM : TUNER PACK,FM TUNER.PK : FRONT-ENDTUNER PACK VR : ROTARY POTENTIOMETER VR.MTR : POTENTIOMETER WITH MOTOR VR.SW : POTENTIOMETER WITH ROTARY SW VR.SLIDE : SLIDE POTENTIOMETER VR.TRIM : TRIMMER POTENTIOMETER • ELECTRICAL COMPONENT PARTS WARNING G Components having special characteristics are marked s and must be replaced with parts having specifications equal to those originally installed. ● s印のある部分は、安全確保部品を示しています。部品の交換が必要な場合、パーツリストに記載されている部品を使用してください。 ● 部品価格ランクは、予告なく変更することがあります。 Ref No. Part No. Description Remarks Markets 部　品　名 ランク CRX-E320 ✻ New Parts　＊ 新規部品 Note) The electrical parts available as servicing parts are those in the replacement parts list only. When replacement of any electrical part other than those in the list is necessary, replace the P.C.B. assembly which includes that part. 注） 電気部品リストに記載されている電気部品のみ、サービス部品として供給できます。 電気部品リストに記載されていない電気部品の交換が必要な場合は、その電気部品を搭載している「P.C.B. ASSY」を交換 してください。 * AAX83230 P.C.B. MAIN COP11974J J ＰＣＢ　メイン * AAX83270 P.C.B. MAIN COP11974U U ＰＣＢ　メイン * AAX83260 P.C.B. MAIN COP11974T T ＰＣＢ　メイン * AAX83240 P.C.B. MAIN COP11974K K ＰＣＢ　メイン * AAX83210 P.C.B. MAIN COP11974A A ＰＣＢ　メイン * AAX83220 P.C.B. MAIN COP11974G G ＰＣＢ　メイン * AAX83250 P.C.B. MAIN COP11974L L ＰＣＢ　メイン * IC22 AAX83060 IC RT9702APB CVIRT9702APB ＩＣ * IC23 AAX83110 IC 74ACT04MTR HVI74ACT04MTR ＩＣ * IC25 AAX83070 IC STK4142MK2 CVISTK4142MK2 ＩＣ * IC26 AAX83120 IC LM1117S-1V5 HVILM1117S-1V5 ＩＣ * IC27 AAX83090 IC TC94A70FG CVITC94A70FG ＩＣ * IC28 AAX83050 IC AK4385ET CVIAK4385ET ＩＣ * IC29 AAX83140 IC TA2125AFG HVITA2125AFG ＩＣ * IC30 AAX83130 IC NJM2068MDTE1 HVINJM2068MDTE1 ＩＣ * IC31 AAX83130 IC NJM2068MDTE1 HVINJM2068MDTE1 ＩＣ * IC32 AAX83150 IC TC9163CFG HVITC9163CFG ＩＣ * IC33 AAX83160 IC TDA7313NDTR HVITDA7313NDTR ＩＣ IC34 AAX77300 IC 74HCU04 HVI74HCU04AFNG ロジックＩＣ * JK21 AAX83570 CN.OPT TOTX177L HJSTOTX177L 光ファイバー送信器 * JK22 AAX83170 JACK.PIN 4P AUX IN/OUT CJJ4P014W ＩＮ／ＯＵＴ端子 * JK23 AAX83390 SP.TERM 4P CJJ5P012Z スピーカー端子 * JK24 AAX83430 JACK.PIN 1P SUBWOOFER CJJ4M046Z ピンジャック１Ｐ * RY50 AAX83560 RELAY DC12V 2C2P CSL4A016ZU リレー RY51 AAX79390 RELAY G5PA28 CSL3A017ZU リレー * AAX83200 P.C.B. FRONT/SMPS COP11972B ＰＣＢ　フロント／ＳＭＰＳ FiP1 AAX73210 FIP HCA-17SM03T HFLHCA-17SM03T ＦＩＰ * JK81 AAX83470 JACK.PHONE 3.5mm 2P PHONES HJJ2D003Z ホーンジャック　３．５ｍｍ * JK82 AAX83470 JACK.PHONE 3.5mm 2P PORTABLE HJJ2D003Z ホーンジャック　３．５ｍｍ * JK83 AAX83300 JACK 4P CJJ9X003Y ＵＳＢ端子 * RC81 AAX83550 SENSER.RC KSM603TH2A HRVKSM603TH2A リモコン受光ユニット SW81-88 AAX74630 SW. TACT SKHV10910G CST1A012ZT タクトスイッチ 01 VR81 AAX74610 VR.ENCODER CSR2A036Z エンコーダーＶＲ 04 VR82 AAX74600 SW.ENCODER HSR2A025Z エンコーダーＳＷ 05 * AAX83190 P.C.B. CONNECTOR COP11973B ＰＣＢ　コネクタ w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 2 A B C D E F G H I J 1 3 4 5 7 CRX-E320/NX-E700 6 30 200 200-1 202 P12 U, T, L, J models 202 203 K, A, G models C8 C2-2 C2-1 P1 M1 M2 M3 S2 S12 P2 P2 P3 RIGHT P4 LEFT P4 S5 S5 P5 P6 C1 (1) S3 S3 P13 P13 CB81 M11 S10 S10 S1 S1 S7 S7 S6 C2 P8 C1 (2) S4 CB31 C4 (1) C4 (2) C5 S6 S6 S6 S7 S7 S4 S6 S6 P7 S4 P7 P10 CB45 P11 C1 (3) C3 S4 M4 S9 S9 S11 S11 S8 S7 • OVERALL ASS’Y CRX-E320 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com CRX-E320/NX-E700 31 P12 AAX73380 CORD STOPPER KHR1A028 コードストッパー 01 * P13 AAX83020 RUBBER FL CHG1A364 ＦＬゴムパッド S1 AAX73500 BIND HEAD B-TIGHT SCREW GD,SI 3x8 MFZN2W3 CTB3+8JFC バインドＢタイトネジ 01 S1 AAX78380 BIND HEAD B-TIGHT SCREW BL 3x8 MFZN2B3 CTB3+8JFZR バインドＢタイトネジ S2 AAX74180 BIND HEAD BONDING B-T. SCREW GD,SI 3x8 MFZN2W3 CTBD3+8JFC ボンディングＢタイトネジ 01 S2 AAX80490 BIND HEAD BONDING B-T. SCREW BL 3x8 MFZN2B3 CTBD3+8JFZR ボンディングＢタイトネジ 01 S3 AAX78410 BIND HEAD P-TIGHT SCREW 3x10 MFZN2Y CTB3+10GR バインドＰタイトネジ 01 * S4 AAX83290 PW HEAD B-TIGHT SCREW 3x8 MFZN2Y CTW3+6JR ＰＷヘッドＢタイトネジ S5 AAX80140 PW HEAD B-TIGHT SCREW 3x8 MFZN2Y CTW3+8JR ＰＷヘッドＢタイトネジ 01 S6 AAX80420 BIND HEAD B-TIGHT SCREW 3x6 MFZN2Y CTB3+6JR バインドＢタイトネジ 01 S7 AAX78390 BIND HEAD B-TIGHT SCREW 3x8 MFZN2Y CTB3+8JR バインドＢタイトネジ 01 * S8 AAX83280 PW HEAD B-TIGHT SCREW 3x18 MFZN2Y CTW3+18JR ＰＷヘッドＢタイトネジ S9 AAX80430 BIND HEAD SCREW 3x6 MFZN2B3 CTB3+6FFZR バインド小ネジ 01 S10 AAX73930 PW HEAD B-TIGHT SCREW GD,SI 3x8 MFZN2W3 CTW3+8JFC ＰＷヘッドＢタイトネジ 01 S10 AAX78230 PW HEAD B-TIGHT SCREW BL 3x8 MFZN2B3 CTW3+8JFZR ＰＷヘッドＢタイトネジ 01 S11 AAX78400 BIND HEAD P-TIGHT SCREW 3x10 MFZN2B3 CTB3+10GFZR バインドＰタイトネジ 01 S12 AAX80600 FLAT HEAD B-TIGHT SCERW 3x8 MFZN2Y CTS3+8JR 皿Ｂタイトネジ 01 ACCESSORIES 付属品 * 200 WK015500 REMOTE CONTROL CARTCRXE320 JUTKAL リモコン * 200 WK015400 REMOTE CONTROL CARTCRXE320G G リモコン 200-1 AAX57560 BATTERY COVER 103RRS-141-07L 103RRS-141-07L 電池蓋 04 202 AAX76680 INDOOR FM ANTENNA 1pc CSA1A019Z JUTL ＦＭ簡易アンテナ 03 202 AAX73240 INDOOR FM ANTENNA 1pc CSA1A018Z KAG ＦＭ簡易アンテナ 03 203 AAX73180 AM LOOP ANTENNA 1pc CSA1A020Z ＡＭループアンテナ 04 BATTERY R6,AA,UM-3 2pcs 単３乾電池 s C1 AAX83200 P.C.B. ASS'Y FRONT/SMPS COP11972B ＰＣＢ　フロント・ＳＭＰＳ C2 AAX78140 CD MECHANISM UNIT KSL2130CCMZ CJDKSL2130CCMZ ＣＤメカニズムユニット 17 * C2-1 AAX82720 PICK UP UNIT KSS-213C KSM2130CCM ピックアップユニット C2-2 AAX78500 BELT 9A07980900 ベルト * s C3 AAX83190 P.C.B. ASS'Y CONNECTOR COP11973B ＰＣＢ　コネクタ * C4 AAX83230 P.C.B. ASS'Y MAIN COP11974J J ＰＣＢ　メイン * C4 AAX83270 P.C.B. ASS'Y MAIN COP11974C U ＰＣＢ　メイン * C4 AAX83260 P.C.B. ASS'Y MAIN COP11974T T ＰＣＢ　メイン * C4 AAX83240 P.C.B. ASS'Y MAIN COP11974K K ＰＣＢ　メイン * C4 AAX83210 P.C.B. ASS'Y MAIN COP11974D A ＰＣＢ　メイン * C4 AAX83220 P.C.B. ASS'Y MAIN COP11974B G ＰＣＢ　メイン * C4 AAX83250 P.C.B. ASS'Y MAIN COP11974L L ＰＣＢ　メイン * C5 AAX83400 MODULE TUNER MV114MA1-17 CNVMV114MA1-17 チューナーモジュール s C8 AAX74330 POWER CABLE 2m CJA2J049ZA J 電源コード 04 s C8 AAX74370 POWER CABLE 2m CJA523FBYA U 電源コード s C8 AAX74350 POWER CABLE 2m CJA2N047ZA T 電源コード s C8 AAX74320 POWER CABLE 2m CJA2D073Z K 電源コード s C8 AAX74360 POWER CABLE 2m CJA2S048ZA A 電源コード s C8 AAX74310 POWER CABLE 2m CJA2B043ZA GL 電源コード * CB31 AAX83330 FLEXIBLE FLAT CABLE 16P 150mm P=1.0 CWC4F1A16A150A カード電線 * CB45 AAX83320 FLEXIBLE FLAT CABLE 13P 60mm P=1.25 CWC4C4A13B060B カード電線 * CB81 AAX83340 FLEXIBLE FLAT CABLE 21P 180mm P=1.0 CWC4F4A21A180B カード電線 M1 AAX74020 JOG KNOB ASS'Y GD CGK1A114YA ジョグノブＡＳＳＹ M1 AAX80880 JOG KNOB ASS'Y BL CGK1A114XA ジョグノブＡＳＳＹ 09 M1 AAX74030 JOG KNOB ASS'Y SI CGK1A114ZA ジョグノブＡＳＳＹ 07 M2 AAX74160 VOLUME KNOB ASS'Y GD CGK1A113YA ボリュームノブＡＳＳＹ M2 AAX80920 VOLUME KNOB ASS'Y BL CGK1A113XA ボリュームノブＡＳＳＹ 09 M2 AAX74170 VOLUME KNOB ASS'Y SI CGK1A113ZA ボリュームノブＡＳＳＹ 07 * M3 AAX83450 PANEL AL FRONT GD CKM1A183ZC55 フロントパネル * M3 AAX83460 PANEL AL FRONT BL CKM1A183ZC59 フロントパネル * M3 AAX83440 PANEL AL FRONT SI CKM1A183ZC54 フロントパネル * M4 AAX83500 PANEL REAR CKF1A325V J リアパネル * M4 AAX83520 PANEL REAR CKF1A325X U リアパネル * M4 AAX83490 PANEL REAR CKF1A325U T リアパネル * M4 AAX83480 PANEL REAR CKF1A325T K リアパネル * M4 AAX83530 PANEL REAR CKF1A325Y A リアパネル * M4 AAX83540 PANEL REAR CKF1A325Z G リアパネル * M4 AAX83510 PANEL REAR CKF1A325W L リアパネル * M11 AAX83410 TOP COVER GD CKC1A167D7 トップカバー M11 AAX80890 TOP COVER BL CKC1A167B11 トップカバー 10 M11 AAX74040 TOP COVER SI CKC1A167G33 トップカバー 11 * P1 AAX83010 WINDOW FL CGU1A379Y ＦＬウィンドウ P2 AAX74090 KNOB ORNAMENT STANDBY/ON GD CGR1A388M9D6 ノブ飾り P2 AAX79300 KNOB ORNAMENT STANDBY/ON BL CGR1A388K128 ノブ飾り 01 P2 AAX74080 KNOB ORNAMENT STANDBY/ON SI CGR1A388M7G5 ノブ飾り 02 * P3 AAX83180 IR LENS GD, SI CGU1A380 ＩＲレンズ * P3 AAX83180 IR LENS BL CGU1A380A26 ＩＲレンズ P4 AAX73980 SIDE BAR CGR1A385 サイドバー 02 * P5 AAX83370 SUB PANEL ASS'Y GD CGWCRXE320G サブパネルＡＳＳＹ * P5 AAX83360 SUB PANEL ASS'Y BL CGWCRXE320B サブパネルＡＳＳＹ * P5 AAX83380 SUB PANEL ASS'Y SI CGWCRXE320S サブパネルＡＳＳＹ * P6 AAX83040 SHEET FL ORANGE GD CMZ1A124Y ＦＬシート P6 AAX83030 SHEET FL BLUE BL, SI CMZ1A103X ＦＬシート P7 AAX74300 FOOT CKL1A191 脚 01 * P8 AAX83420 TRAY LID (DOOR ORNAMENT) GD CGR1A394M9D6 トレイリッド P8 AAX79280 TRAY LID (DOOR ORNAMENT) BL CGR1A394K128 トレイリッド 05 P8 AAX79290 TRAY LID (DOOR ORNAMENT) SI CGR1A394M7G5 トレイリッド * P10 AAX83350 GUIDE CABLE CMH1A265 ケーブルガイド * P11 AAX83310 INSULATOR SMPS CMX1A215 インシュレーターＳＭＰＳ ✻ New Parts　＊ 新規部品 Ref No. Part No. Description Remarks Markets 部　品　名 ランク Ref No. Part No. Description Remarks Markets 部　品　名 ランク ✻ New Parts　＊ 新規部品 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 2 A B C D E F G H I J 1 3 4 5 7 CRX-E320/NX-E700 6 32 Ref No. Part No. Description Remarks Markets 部　品　名 ランク 1 WG237700 CABINET ASS'Y BL キャビネットＡＳＳＹ 2 WG237800 FRONT GRILLE ASS'Y フロントグリルＡＳＳＹ 3 XM275B00 DRIVER TWEETER 2.5cm 5Ω JA05U3 スピーカーユニット 4 XZ668C00 DRIVER WOOFER 11cm 6Ω JA1151 スピーカーユニット 7 V9504600 NETWORK ASS'Y ネットワークＡＳＳＹ 7-1 V6055400 ELECTROLYTIC CAP 8.2uF 63V ＢＰケミコン 04 7-2 V6367500 ELECTROLYTIC CAP 3.3uF 63V ＢＰケミコン 7-3 V9507500 CEMENT RESISTOR 2.7Ω 5W セメント抵抗 01 12 V5361400 TERMINAL CAP S06E RED ターミナルキャップ 13 V5361500 TERMINAL CAP S06E BLACK ターミナルキャップ 21 WE963200 FLAT HEAD WOOD SCREW 3.5x20 MFZN2B3 皿木ネジ 22 V9506100 HEXAGON HEAD WOOD SCREW 4x25 MFZN2BL ６角穴付き木ネジ ACCESSORIES 付属品 30 V9826900 SPEAKER CABLE 4m 1pc スピーカーケーブル • OVERALL ASS’Y 22 22 2 3 4 21 7-1 7-2 7-3 30 1 30 12 7 13 INPUT NETWORK CIRCUIT DIAGRAM TWEETER WOOFER R1 L1 1.0 mH C2 3.3 uF C1 8.2 uF L2 0.27 mH 2.7 ohms NX-E700 ✻ New Parts　＊ 新規部品 I REMOTE CONTROL • PANELS 1 3 4 5 6 7 8 9 10 11 15 16 17 18 19 20 21 22 23 24 33 34 35 31 32 39 36 37 40 41 42 43 44 45 46 47 25 26 12 13 14 2 U, T, K, A, L, J models G model • KEY LAYOUT w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 33 CRX-E320/NX-E700 CRX-E320/ NX-E700 Key no. Common code Function AMP 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 31 32 33 34 35 36 37 39 40 41 42 43 44 45 46 47 78-0F 78-00 78-11 78-12 78-13 78-14 78-15 78-16 78-17 78-18 78-19 78-10 78-0E 78-BA 78-0B 78-0C 78-BE 78-B9 78-01 78-07 78-04 78-02 78-03 78-0A 78-4E 78-4F 78-8E 78-8F 78-9F 78-9E 78-C1 78-1B 78-1C 78-9C 78-1E 78-1F 78-B6 78-4B 78-4A 78-49 78-BC 78-DF STANDBY/ON OPEN/CLOSE FFFFF 1 2 3 4 5 6 7 8 9 0 INDEX DIMMER PROG REPEAT A-B PAUSE DDDDD STOP A AA AA RANDOM SKIP/SEARCH - T T T T T PLAY W WW WW SKIP/SEARCH + Y Y Y Y Y TIME/INFO DISPLAY SLEEP FOLDER HHHHH FOLDER GGGGG FILE Q QQ QQ FILE W WW WW ENTER PRESET HHHHH PRESET GGGGG MUTE VOLUME + VOLUME - BAND TUNER CD AUX USB PORTABLE CD (K44) – OPEN/CLOSE FFFFF 1 2 3 4 5 6 7 8 9 0 INDEX – PROGRAM REPEAT Repeat A-B PAUSE DDDDD STOP A AA AA SHUFFLE SKIP/SEARCH - T T T T T PLAY W WW WW SKIP/SEARCH + Y Y Y Y Y TIME/INFO – – FOLDER HHHHH FOLDER GGGGG FILE Q QQ QQ FILE W WW WW ENTER – – – – – – – – – – – TUNER (K43) – – 1 2 3 4 5 6 7 8 – – – – – – (FREQ/TEXT) – (MODE) (START) – – – – – – – – – – – PRESET/CH HHHHH PRESET/CH GGGGG – – – BAND – – – – – USB (K46) – – 1 2 3 4 5 6 7 8 9 0 – – PROG REPEAT – PAUSE DDDDD CLEAR / STOP A AA AA RANDOM SKIP/SEARCH - T T T T T PLAY W WW WW SKIP/SEARCH + Y Y Y Y Y TIME/INFO – – FOLDER HHHHH FOLDER GGGGG FILE Q QQ QQ FILE W WW WW ENTER – – – – – – – – – – – • KEY CODE * (xxx): G model www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com CRX-E320/NX-E700 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com
