- 1 - E-mail: http://www.LGEservice.com/techsup.html COLOR MONITOR SERVICE MANUAL MODEL:  W1943TB (W1943TB-PFT.A**NAPH for LGD TLC1, W1943TB-PFT.A**VAPH for AUO V00) **Sales Market CAUTION BEFORE SERVICING THE UNIT, READ THE SAFETY PRECAUTIONS IN THIS MANUAL.                                                                                                                                                               *To apply the Novatek Chip.  http://www.wjel.net - 2 - CONTENTS SPECIFICATIONS ...................................................2 PRECAUTIONS .......................................................3 TIMING CHART .......................................................7 DISASSEMBLY ........................................................8 BLOCK DIAGRAM...................................................11 DISCRIPTION OF BLOCK DIAGRAM .................. 13 ADJUSTMENT ...................................................... 15 SERVICE MODE ......................................................... 17 TROUBLESHOOTING GUIDE .............................. 18 WIRING DIAGRAM ................................................... 24 EXPLODED VIEW...................................................... 25 REPLACEMENT PARTS LIST ................................. 27 DIFFERENT PARTS LIST….......................................... 35 SCHEMATIC DIAGRAM......................................... 36 SPECIFICATIONS 1. LCD CHARACTERISTICS Type: matrix-TFT Color LCD Module Active Display Area: 18.51 inches Pixel Pitch: 0.3 (H) x 0.3 (V)mm Color Depth: 16.7M colors Size: 430.4(H) x 254.6(V) x 13.0(D) mm(Typ.) Interface: LVDS 1Port Surface Treatment: Hard-coating(3H), Anti-Glare Operating Mode: Normally White, Transmissive mode Backlight unit: 2 CCFL 2. OPTICAL CHARACTERISTICS 2-1. Viewing Angle by Contrast Ratio > 10 Left : 70°min, 85°(Typ) Right : 70°min, 85°(Typ) Top :60° min, 75°(Typ) Bottom : 70°min,85°(Typ) 2-2.Luminance :250Cd / m2 (min), 300Cd / m2 (Typ) -6500K; 170Cd / m2 (min) -9300K 2-3. Contrast Ratio: 600(min), 1000(Typ) 3. SIGNAL (Refer to the Timing Chart) 3-1. Sync Signal Type: Separate Sync, SOG (Sync On Green) / Digital 3-2. Video Input Signal 1) Type: R, G, B Analog 2) Voltage Level: 0~0.7 Vp-p 3) Input impedance: 75 Ω 3-3. Operating Frequency Horizontal: 30 ~ 61kHz Vertical: 56 ~ 75Hz 4. Max. Resolution D-sub Analog: VESA 1360 x 768 @ 60 Hz 5. POWER SUPPLY 5-1. Power: AC 100-240V~ 50/60Hz 0.8A 5-2. Power Consumption On Mode: 21 W(Typ.) Sleep Mode: ≤ 1 W Off Mode: ≤ 1 W 6. ENVIRONMENT 6-1. Operating Temperature: 10°C~35°C Humidity: 10 % to 80 % non-Condensing 6-2. Storage Temperature: -20°C to 60 °C Humidity: 5 % to 90 % non-Condensing 6-3. MTBF: 70000 Hours (Not include panel) Lamp Life: ≤ 50000 Khrs 7. DIMENSIONS (with Stand) Width: 44.90 cm (17.68 inches) Depth: 18.30 cm (7.20 inches) Height: 29.05 cm (11.44 inches) 8. WEIGHT (excl. packing) Weight: 3.3 kg (7.28 lbs) http://www.wjel.net   - 3 - http://www.wjel.net   - 4 - http://www.wjel.net   - 5 - http://www.wjel.net   - 6 - http://www.wjel.net   - 7 - TIMING CHART mode section polarity DOT CLOCK [MHz] Frequency [kHz]/[Hz] Total Period(E) Display (A) Front Porch (D) Sync. (C) Back Porch (B) Resol- ution H(Pixels) - 31.468 900 720 18 108 54 1 V(Lines) + 28.321 70.08 449 400 12 2 35 720 X 400 H(Pixels) - 31.469 800 640 16 96 48 2 V(Lines) - 25.175 59.94 525 480 10 2 33 640 x 480 H(Pixels) - 37.5 840 640 16 64 120 3 V(Lines) - 31.5 75 500 480 1 3 16 640 x 480 H(Pixels) + 37.879 1056 800 40 128 88 4 V(Lines) + 40.0 60.317 628 600 1 4 23 800 x 600 H(Pixels) + 46.875 1056 800 16 80 160 5 V(Lines) + 49.5 75.0 625 600 1 3 21 800 x 600 H(Pixels) +/- 49.725 1152 832 32 64 224 6 V(Lines) +/- 57.283 74.55 667 624 1 3 39 832 x 624 H(Pixels) - 48.363 1344 1024 24 136 160 7 V(Lines) - 65.0 60.0 806 768 3 6 29 1024 x 768 H(Pixels) - 60.123 1312 1024 16 96 176 8 V(Lines) - 78.75 75.029 800 768 1 3 28 1024 x 768 H(Pixels) + 47.712 1792 1360 64 122 256 9 V(Lines) + 85.5 60.015 795 768 3 6 18 1360 x768 http://www.wjel.net   - 8 - DISASSEMBLY-Set #1 Put the monitor on a soft flat. #2 Revolve the release button. #3 Consequently, pull the base directly. #4   The base. #5 Put the front cover upward. Then let the all latches are separated. #6 Put the front face down, disassembly back cover. http://www.wjel.net   - 9 - #7 Pull the key board out of bezel. ＃8 Disassembly the bezel. #9 Disassembly the LVDS cable. #10 Disassemble the connector. #11 Main board and power board. #12 The panel. http://www.wjel.net   - 10 - #13 Rear cover and hinge ASS’Y. #14 Disassemble the rear cover and hinge ASS’Y. #15 Disassemble the hinge and stand. #16 Hinge top, hinge and stand. http://www.wjel.net   - 11 - BLOCK DIAGRAM http://www.wjel.net   - 12 - BLOCK DIAGRAM-POWER Power Inverter EMI filter Rectification  Transformer 5V/14.5V output OVP Feedback control circuit Switching circuit (PWM control IC & MOSFER) OVP protect circuit Diode rectifier  Starting resistor 14.5V Rush prevention ON/OFF DIM Push-pull circuit Transformer conversion LC resonance VDDA ON/OFF circuit PWM IC OZ9938GN Feedback circuit OVP circuit 2 CCFL lamps Sampling Lamp open protection DIM circuit 14.5V 5V 100~240V http://www.wjel.net   - 13 - DESCRIPTION OF BLOCK DIAGRAM 1. Video Controller Part. This part amplifies the level of video signal for the digital conversion and converts from the analog video signal to the digital video signal using a pixel clock. The pixel clock for each mode is generated by the PLL. The range of the pixel clock is from 25MHz to 85.5MHz. This part consists of the Scalar, ADC converter, TMDS receiver and LVDS transmitter. The Scalar gets the video signal converted analog to digital, interpolates input to 1360 X 768 resolution signal and outputs 8-bit R, G, B signal to transmitter. 2. Power Part. This part consists of the one 3.3V, and one 1.8V regulators to convert power which is provided 5V in Power board. 14.5V is provided for inverter, 5V is provided for LCD panel. Also, 5V is converted 3.3V and 1.8V by regulator. Converted power is provided for IC in the main board. The inverter converts from DC 14.5V to AC 700Vrms and operates back-light lamps of module. 3. MICOM Part. This part is including video controller part. And this part consists of Reset IC and the Micom. The Micom distinguishes polarity and frequencies of the H/V sync are supplied from signal cable. The controlled data of each mode is stored in scalar. http://www.wjel.net   - 14 - LIPS Board Block Diagram Operation description_LIPS 1. EMI components. This part contains of EMI components to comply with global marketing EMI standards like FCC, VCCI CISPR, the circuit included a line-filter, across line capacitor and of course the primary protection fuse. 2. Input rectifier and filter. This part function is for transfer the input AC voltage to a DC voltage through a bridge rectifier and a bulk capacitor. 3. Energy Transfer. This part function is for transfer the primary energy to secondary through a power transformer. 4. Output rectifier and filter. This part function is to make a pulse width modulation control and to provide the driver signal to power switch, to adjust the duty cycle during different AC input and output loading condition to achieve the dc output stabilized, and also the over power protection is also monitor by this part. 5. Photo-Coupler isolation. This part function is to feed back the DC output changing status through a photo transistor to primary controller to achieve the stabilized DC output voltage. 6. Signal collection. This part function is to collect the any change from the DC output and feed back to the primary through photo transistor. http://www.wjel.net   - 15 - ADJUSTMENT Windows EDID V1.0 User Manual Operating System: DOS, windows98, 2000, XP 1. Parallel port setting Enter your bios, and do as followings. a) Integrated peripheral b) Super IO Device c) Parallel port mode you should set the” parallel port mode” to SPP for using the DOS EDID tool surely. 2. EDID Write 1、Connect the signal line of monitor with DDC recorder. 2、Choose the DDC RECORD program, and it shows on the screen, the choose the correct source base on the monitor. 3、Click “LoadFile” ,then key in the manufacturer name、model name、product code, then choose the correct model name base on the monitor.(as Fig.2) 4、Scan serial No. to DDC recorder by Bar Reader, then read again in the Verify SN. 5、According to the message of DDC program, when the picture as fig.1 appears, it show DDC record has finished. Fig.1 http://www.wjel.net   - 16 - Please check Manufacturer Name、Vendor Assigned Code、 Monitor Name、 Serial Number：*****[???????? ******] (it must be the same as Bar Code)、 Week of Manufacture：**、Year of Manufacture：****、Check sum：** (It must be the same as the last byte of data table, as follows picture shows). Above of all must be right, then if it shows the green “PASS”, it means record succeeds ,the red “Fail” means record fails; then check the power supply and signal line, and ensure they are connected well ,then do DDC record again from the third step.   Fig.2 http://www.wjel.net   - 17 -       1) Turn off the power switch at the front side of the display. 2) Wait for about 5 seconds and press MENU, POWER switch with 1 second interval. 3) The SVC OSD menu contains additional menus that the User OSD menu as described below. a) CLEAR ETI: To initialize using time. b) Auto Color: W/B balance and automatically sets the gain and offset value. c) AGING: Select Aging mode (on/off). d) PANEL: used panel type e) NVRAM INIT: NO f) R/G/B-9300K: Allows you to set the R/G/B-9300K value manually. g) R/G/B-6500K: Allows you to set the R/G/B-6500K value manually. h) R/G/B-Offset: Allows you to set the R/G/B-Offset value manually. (Analog Only) i) R/G/B-Gain: Allows you to set the R/G/B-Gain value manually. (Analog Only) Figure 1 Cable Connection for Micom uploading SERVICE MODE  Connect to the PC Connect to the monitor  http://www.wjel.net   - 18 - TROUBLESHOOTING GUIDE No Power (Power Indicator Off) Please reinsert and make sure the AC of 100-240v is normal Measure C704 (+) =1.8V U703 PIN2=3.3V Check the Adapter/Inverter section Check CN701 or replace C704, and U703 NO NO YES YES 1. NO POWER  Check X401 oscillate waveforms are normal Replace X401   Replace U401   NO YES http://www.wjel.net   - 19 - 2. NO RASTER (OSD IS NOT DISPLAY)-LIPS  LIPS Check C704 (+) 1.8V? 1. Check C704 2. TROUBLE IN SCALER IC  NO No Raster (OSD Is Not Displayed) Check U703 PIN 2 =3.3V? Check CN701 PIN 6, PIN7 =5V? Check power board and find out a short point as penning each power line 1. Check U703 2. Check C706,C707 NO NO YES YES YES Check CN701 PIN 6, PIN7 =5V? YES NO Check BL ON/OFF pulse as contacting scope http://www.wjel.net   - 20 - 3. NO RASTER (OSD IS NOT DISPLAY)-MSTAR  1. Check C420 C421 2. Check X401 3. TROUBLE IN SCALER IC SCALER PIN 127, 128 OSCILLATES AS 12MHZ? No Raster (OSD Is Not Displayed) CHECK CONNECTION LINE FROM D-SUB TO SCALER TROUBLE IN CABLE OR LCD MODULE NO YES YES NO SCALER IC PIN 41 H SYNC ? PIN 42 V SYNC? http://www.wjel.net   - 21 - 4. TROUBLE IN DPM  TROUBLE IN DPM SCALER IC PIN 41 H SYNC? PIN 42 V SYNC? CHECK H/V SYNC LINE TROUBLE IN CABLE OR LCD MODULE NO YES http://www.wjel.net   - 22 - 5. POWER Check U901 pin 6 Vcc is 13v? Check D902,C911  Check U901, T901,D906,D905,ZD903,ZD902,U902,U903 NO YES YES No Power (Power Indicator Off) Check AC line volt Check the voltage of C907(+) Check start voltage for the pin1 of U901 Check AC line Check F901, BD901 Check D901, R903, R904,R905,U901 NO YES NO YES NO Check U901 PIN5 output is PWM? Check D904,Q901  NO http://www.wjel.net   - 23 - 6. RASTER  Unplug backlight connector wire, check PT801 pin7/pin8 = 650V? Replace PT801 NO NO YES Check PT801 pin7/pin8= 650V? Replace backlight Check Q806 pin5, pin6 is 14.5V? Cut all the pin connector of Q806, check C811 (+) =14.5V? Replace Q806 Check C807, C809, C810 Replace IC801 NO NO Raster (Lamp Off) Check C811 (+) =14.5V Check ON/OFF signal CheckIC801 pin 2=5V?  Check power section Check Interface section or main board  Check C807, C809, C810 Check IC801 pin 5/pin6 NO NO NO YES YES Check IC801 Pin1/pin15 have the output of sawtooth YES NO YES YES NO YES NO http://www.wjel.net   - 24 - WIRING DIAGRAM 095G820H 6D515 095G8018 3XH55 095G 825 9W524 http://www.wjel.net   - 25 - EXPLODED VIEW     http://www.wjel.net   - 26 - EXPLODED VIEW PARTS LIST Ref. No. TPV Part No. LGE Part No. Description 010 705GQ9CS014 ACQ74060001 BEZEL ASSY 020 KEPC8QG2 EBU60704501 KEY BOARD 750GLG185W1C12M0LG EAJ60134501 PANEL LM185WH1-TLC1 NJ LGD EAJ59066901 030 750GLU185X1012N000 EAJ59066902 PANEL M185XW01 V00 SZ AUO 756GQ8CB KL010 EBU60705001(FOR LGD MODULE) MAIN BOARD-CBPCRNDLGQ1 040 756GQ8CB KL011 EBU60704601(FOR AUO MODULE) MAIN BOARD-CBPCRNDLGQ1 050 PWPC8921MYE1 EBU60704301 POWER BOARD Q15G0414101 MDQ61891301 MAINFRAME 060 Q15G0414301 MDQ61891302 MAINFRAME 705GQ934026 ACQ74060101 REAR COVER/HINGE ASS'Y 070 705GQ934028 ACQ74060102 REAR COVER/HINGE ASS'Y 080 705GQ9CS015 ACQ74060201 BASE ASSY 090 095G8018 3XH55 COV30101401 LVDS CABLE 100 089G 728HAA 2G NA SIGNAL CABLE 110 089G1748CAA AC NA SIGNAL CABLE DVI COMLINK 120 089G421A18N IS EAD37992101 POWER CORD http://www.wjel.net   - 27 - REPLACEMENT PARTS LIST DATE: 2009. 3. 6 T8RGNDNBMWLFHN *S *AL LOC. NO. PART NO. DESCRIPTION MAIN BOARD CAPACITOR C102 065G0402473 12 CHIP 0.047UF 16V X7R C103 065G0402220 31 CHIP 22PF 50V NPO C104 065G0402220 31 CHIP 22PF 50V NPO C105 065G0402509 31 CHIP 5PF 50V NPO C106 065G0402473 12 CHIP 0.047UF 16V X7R C107 065G0402102 32 1000PF +-10% 50V X7R C108 065G0402473 12 CHIP 0.047UF 16V X7R C109 065G0402509 31 CHIP 5PF 50V NPO C110 065G0402473 12 CHIP 0.047UF 16V X7R C111 065G0402473 12 CHIP 0.047UF 16V X7R C113 065G0402509 31 CHIP 5PF 50V NPO C114 065G0402473 12 CHIP 0.047UF 16V X7R C115 065G040210412T CHIP 0.1UF 16V X7R C117 065G0402224 17 CAP CER 0.22UF -20%-80% C301 065G040210412T CHIP 0.1UF 16V X7R C302 065G0402224 17 CAP CER 0.22UF -20%-80% C303 065G0603105 12 CHIP 1UF 16VX7R 0603 C304 065G040210412T CHIP 0.1UF 16V X7R C305 067G 2151014PB EC 100UF M 25V 6.3*11MM C401 065G0402224 17 CAP CER 0.22UF -20%-80% C403 065G060310517T MLCC 0603 CAP 1UF Z 16V Y5V C404 065G060310517T MLCC 0603 CAP 1UF Z 16V Y5V C406 065G040210412T CHIP 0.1UF 16V X7R C407 065G040210412T CHIP 0.1UF 16V X7R C410 065G040210412T CHIP 0.1UF 16V X7R C412 065G040210412T CHIP 0.1UF 16V X7R C413 065G040210412T CHIP 0.1UF 16V X7R C420 065G0402220 31 CHIP 22PF 50V NPO C421 065G0402220 31 CHIP 22PF 50V NPO C422 065G040210412T CHIP 0.1UF 16V X7R C423 065G040210412T CHIP 0.1UF 16V X7R C430 065G040210412T CHIP 0.1UF 16V X7R C431 065G040210412T CHIP 0.1UF 16V X7R C434 065G040210412T CHIP 0.1UF 16V X7R http://www.wjel.net   - 28 - C435 065G040210412T CHIP 0.1UF 16V X7R C438 065G0805105 12 1UF +-10% 6V X7R C439 065G060310517T MLCC 0603 CAP 1UF Z 16V Y5V C440 065G0805475A7Z CAP CHIP 4.7UF 10V Y5V -20%~+80% C442 065G040210412T CHIP 0.1UF 16V X7R C446 065G040210412T CHIP 0.1UF 16V X7R C447 065G040210412T CHIP 0.1UF 16V X7R C448 065G060310517T MLCC 0603 CAP 1UF Z 16V Y5V C702 065G040210412T CHIP 0.1UF 16V X7R C704 067G 2151014PB EC 100UF M 25V 6.3*11MM C707 067G 2151014PB EC 100UF M 25V 6.3*11MM C708 065G040210412T CHIP 0.1UF 16V X7R C709 065G040210412T CHIP 0.1UF 16V X7R DIODE D102 093G 64 42 PP BAV70 SOT-23 ZD104 093G 39GA01 T RLZ5.6B IC U102 056G1133 34 1 IC M24C02-RMN6TP 2KB SO-8 U103 056G 662502 IC ESD AZC199-04S SOT23-6L U104 056G 662502 IC ESD AZC199-04S SOT23-6L U105 056G 662502 IC ESD AZC199-04S SOT23-6L U106 056G 662502 IC ESD AZC199-04S SOT23-6L U107 056G 662502 IC ESD AZC199-04S SOT23-6L U401 056G 562584 IC NT68667FG/C QFP-128L U402 056G1133 81 SST25LF020A-33-4C-SAE SMTCR-U402 100GKNG8001N11 MCU ASS'Y-056G1133 81 U703 056G 563 52 IC AP1117D33L-13 TO252-3L DIODES TRANSISTOR Q301 057G 763 1 A03401 SOT23 BY AOS(A1) Q302 057G 417 12 T KEC 2N3904S-RTK/PS Q401 057G 417 13 T KEC 2N3906S-RTK/PS Q701 057G 417 12 T KEC 2N3904S-RTK/PS RESISTOR R101 061G0402101 RST CHIPR 100 OHM +-5% 1/16W R102 061G0603000 RST CHIP MAX 0R05 1/10W R103 061G0402101 RST CHIPR 100 OHM +-5% 1/16W R104 061G0402101 RST CHIPR 100 OHM +-5% 1/16W R105 061G0402101 RST CHIPR 100 OHM +-5% 1/16W R106 061G0402222 RST CHIPR 2.2 KOHM +-5% 1/16W R107 061G0402222 RST CHIPR 2.2 KOHM +-5% 1/16W R108 061G0402750 RST CHIPR 75 OHM +-5% 1/16W R109 061G0402101 RST CHIPR 100 OHM +-5% 1/16W R110 061G0402471 RST CHIPR 470 OHM +-5% 1/16W R111 061G0402101 RST CHIPR 100 OHM +-5% 1/16W R112 061G0402750 RST CHIPR 75 OHM +-5% 1/16W R113 061G0402101 RST CHIPR 100 OHM +-5% 1/16W R114 061G0402101 RST CHIPR 100 OHM +-5% 1/16W http://www.wjel.net   - 29 - R115 061G0402101 RST CHIPR 100 OHM +-5% 1/16W R116 061G0402750 RST CHIPR 75 OHM +-5% 1/16W R117 061G0402101 RST CHIPR 100 OHM +-5% 1/16W R118 061G0402101 RST CHIPR 100 OHM +-5% 1/16W R119 061G0402101 RST CHIPR 100 OHM +-5% 1/16W R120 061G0402102 RST CHIPR 1 KOHM +-5% 1/16W R121 061G0402101 RST CHIPR 100 OHM +-5% 1/16W R122 061G0402101 RST CHIPR 100 OHM +-5% 1/16W R126 061G0402100 RST CHIPR 10 OHM +-5% 1/16W R127 061G0402100 RST CHIPR 10 OHM +-5% 1/16W R128 061G0402100 RST CHIPR 10 OHM +-5% 1/16W R129 061G0402100 RST CHIPR 10 OHM +-5% 1/16W R130 061G0402100 RST CHIPR 10 OHM +-5% 1/16W R131 061G0402100 RST CHIPR 10 OHM +-5% 1/16W R132 061G0402100 RST CHIPR 10 OHM +-5% 1/16W R134 061G0402100 RST CHIPR 10 OHM +-5% 1/16W R136 061G0402472 RST CHIPR 4.7 KOHM +-5% 1/16W R137 061G0402472 RST CHIPR 4.7 KOHM +-5% 1/16W R138 061G0402472 RST CHIPR 4.7 KOHM +-5% 1/16W R139 061G0402102 RST CHIPR 1 KOHM +-5% 1/16W R141 061G0402102 RST CHIPR 1 KOHM +-5% 1/16W R142 061G0402000 Y RST CHIP MAX 0R05 1/16W YAGEO R143 061G0402472 RST CHIPR 4.7 KOHM +-5% 1/16W R144 061G0402472 RST CHIPR 4.7 KOHM +-5% 1/16W R301 061G1206221 RST CHIPR 220 OHM +-5% 1/4W R302 061G1206221 RST CHIPR 220 OHM +-5% 1/4W R303 061G0402472 RST CHIPR 4.7 KOHM +-5% 1/16W R304 061G0402223 RST CHIPR 22 KOHM +-5% 1/16W R305 061G0402103 RST CHIPR 10 KOHM +-5% 1/16W R306 061G0402563 RST CHIP 56K 1/16W 5% R308 061G0402103 RST CHIPR 10 KOHM +-5% 1/16W R401 061G0402470 0F RST CHIPR 0402 470 OHM +-1% 1/16W R402 061G0402101 RST CHIPR 100 OHM +-5% 1/16W R403 061G0402103 RST CHIPR 10 KOHM +-5% 1/16W R404 061G0402101 RST CHIPR 100 OHM +-5% 1/16W R405 061G0402103 RST CHIPR 10 KOHM +-5% 1/16W R407 061G0402203 RST CHIP 20K 1/16W 5% R409 061G0402101 RST CHIPR 100 OHM +-5% 1/16W R413 061G0402103 RST CHIPR 10 KOHM +-5% 1/16W R415 061G0402102 RST CHIPR 1 KOHM +-5% 1/16W R416 061G0402102 RST CHIPR 1 KOHM +-5% 1/16W R417 061G0402101 RST CHIPR 100 OHM +-5% 1/16W R418 061G0402121 RST CHIP 120R 1/16W 5% R419 061G0402103 RST CHIPR 10 KOHM +-5% 1/16W R438 061G0402000 RST CHIP MAX 0R05 1/16W R439 061G0402000 RST CHIP MAX 0R05 1/16W R444 061G0402392 RST CHIP 3.9K 1/16W 5% http://www.wjel.net   - 30 - R445 061G0402392 RST CHIP 3.9K 1/16W 5% R446 061G0402000 RST CHIP MAX 0R05 1/16W R462 061G0402105 RST CHIPR 1MOHM +-5% 1/16W R465 061G0402222 RST CHIPR 2.2 KOHM +-5% 1/16W R466 061G0402000 RST CHIP MAX 0R05 1/16W R468 061G0603101 RST CHIPR 100 OHM +-5% 1/10W R702 061G0402102 RST CHIPR 1 KOHM +-5% 1/16W R704 061G0402223 RST CHIPR 22 KOHM +-5% 1/16W R705 061G0402102 RST CHIPR 1 KOHM +-5% 1/16W R706 061G0402101 RST CHIPR 100 OHM +-5% 1/16W R708 061G0402103 RST CHIPR 10 KOHM +-5% 1/16W FB101 071G 59K190 B 19 OHM BEAD FB102 071G 59K190 B 19 OHM BEAD FB103 071G 59K190 B 19 OHM BEAD FB105 071G 59B121 TB160808B FB301 071G 56K121 CHIP BEAD FB401 071G 56G301 EA BEAD 300 OHM FB403 071G 56V301 B CHIP BEAD FCM2012VF-301T07 BULLWILL FB404 071G 56G301 EA BEAD 301 OHM FB406 071G 56V301 B CHIP BEAD FCM2012VF-301T07 BULLWILL FB407 071G 56G301 EA BEAD 302 OHM OTHER X401 093G 2251B J NXS12.000AC30F-BT-2 CN101 088G 35315F XH D-SUB 15PIN VERTICAL CONN WITH SCREW CN102 088G 35424F N DVI 24PIN CONN F WITH SCREW CN302 033G8027 30 H WAFER 30P 2.0MM RIGHT ANGLE CN402 033G3802 7B Y CONNECTOR 7P 2.0 DIP CN701 033G3802 9B Y W WAFER POWER BOARD CAPACITOR C804 065G080510522K T CAP CHIP 0805 1UF K 25V X7R C805 065G0805222 31 0805 2200PF C806 065G080510522K T CAP CHIP 0805 1UF K 25V X7R C807 065G0805103 32 CAP CHIP 0805 10NF K 50V X7R C808 061G0805184 RST CHIPR 180K OHM +-5% 1/8W C809 065G0805473 32 CHIP 0.047UF 50V X7R C810 065G080556131G MLCC 0805 560PF G 50V NPO C811 067G215P4714AV CAP 105℃ 470UF M 25V C813 065G0805102 31 CAP CHIP 0805 1000PF J 50V NPO C814 065G0805105 22 CAP CHIP 0805 1UF K 25V X7R C819 065G0805473 32 CHIP 0.047UF 50V X7R C820 065G0805392 31 CHIP 3900PF 50V X7R 0805 C825 065G 6J1206ET 12PF 5% SL 6KV TDK C826 065G 3J3096ET 3PF,J,3KV,Z5P C828 065G0805104 32 CAP CHIP 0805 0.1UF K 50V X7R C833 065G060347141J Y CAP CHIP 0603 470PF J 100V NPO C834 065G060347141J Y CAP CHIP 0603 470PF J 100V NPO http://www.wjel.net   - 31 - C837 065G0805391 31 CHIP 390PF 50V C838 065G0805473 32 CHIP 0.047UF 50V X7R C839 065G 3J3096ET 3PF,J,3KV,Z5P C841 065G0805392 31 CHIP 3900PF 50V X7R 0805 C900 065G306M3322BP 3300PF 20% C901 065G306M1022BP 1000PF Y1.CAP C902 065G306M1022BP 1000PF Y1.CAP C903 063G107K474 US 0.47UF +-10% C903 006G 31502 1.5MM RIVET C905 067G215S10915T L LOW ESR EC 1UF 450V M 8*11.5MM C906 065G1206104 32 CHIP 0.1UF 25V X7R 1206 C907 067G215Z10115P CAP 105℃ 100UF M 450V C907 006G 31502 1.5MM RIVET C908 065G0603103 12 CHIP 0.01UF 16V X7R C909 065G0603471 32 CHIP 470PF 50V X7R C910 065G0603104 22 CAP CHIP 0603 0.1UF K 25V X7R C911 067G215Y4707KT 47UF 50V C912 065G 2K152 2T6921 CAP CER 1500PF K 2KV Y5P C913 065G1206102 72 CAP CHIP 1206 1000PF K 500V X7R C914 065G1206102 72 CAP CHIP 1206 1000PF K 500V X7R C915 065G0603104 12 CER2 0603 X7R 16V 100N P C916 065G0603102 32 1000PF +-10% 50V X7R C917 067G215P1024AV CAP 105℃ 1000UF M 25V C918 067G215P1023AV CAP 105℃ 1000UF M 16V C919 067G215P1023AV CAP 105℃ 1000UF M 16V C920 067G215P4713AV CAP 105℃ 470UF M 16V C921 065G0603104 12 CER2 0603 X7R 16V 100N P DIODE BD901 093G 50460 28 BRIDGE DIODE KBP208G LITEON D801 093G 64 33 DIO SIG SM BAV99 (PHSE)R D802 093G 64 33 DIO SIG SM BAV99 (PHSE)R D806 093G 64 33 DIO SIG SM BAV99 (PHSE)R D812 093G 6432S 1N4148W D901 093G 5212T52T DIODE 1N4007 DO-41 D902 093G 6038T52T FR103 D903 093G 6026T52T RECTIFIER DIODE FR107 D904 093G 64 1152T 1N4148 D905 093G 60325 DIODE SB5150 5A/150V DO-201AD D906 093G3006 1 1 31DQ06FC3 NIHON INTER ZD901 093G 3916752T MTZJ T-72 16B ZD902 093G 39S 24 T RLZ 5.6B LLDS TRANSISTOR & IC IC801 056G 608 10 IC OZ9938GN-B SOIC-16 Q806 057G 763 6 AO4828 SOIC-8 BY AOS Q811 057G 759 2 RK7002FD5T116 SOT-23 BY ROHM Q812 057G 759 2 RK7002FD5T116 SOT-23 BY ROHM Q901 057G 667 52 FET 2SK4100LS-T 7A/650V TO-220FI(LS) http://www.wjel.net   - 32 - Q901 057G 667 56 MOSFET 7A/650V FMA07N65GX TO-220F Q901 057G 724 11 STP9NK65ZFP Q901 006G 31502 1.5MM RIVET Q902 057G 761 16 TRA KTD1028 KEC U901 056G 379111 IC LD7577 GS SOP-8 U902 056G 139 3A IC PC123Y22FZ0F U903 056G 158 12 KIA431A-AT/P TO-92 RESISTOR NR901 061G 5810T RST NTCR 8 OHM +-20% 4A 13MM THINKING NR901 006G 31502 1.5MM RIVET R807 061G1206220 RST CHIPR 22 OHM +-5% 1/4W R808 061G0805473 RST CHIPR 47K OHM +-5% 1/8W R810 061G0805105 RST CHIPR 1M OHM +-5% 1/8W R812 061G0805103 RST CHIPR 10K OHM +-5% 1/8W R813 061G0805105 RST CHIPR 1M OHM +-5% 1/8W R814 061G0805105 RST CHIPR 1M OHM +-5% 1/8W R815 061G0805104 RST CHIPR 100K OHM +-5% 1/8W R816 061G0805105 RST CHIPR 1M OHM +-5% 1/8W R817 061G0805200 2F RST CHIPR 20 KOHM +-1% 1/8W R818 061G1206330 RST CHIPR 33 OHM +-5% 1/4W R825 061G0805000 RST CHIP MAX 0R05 1/8W R826 061G0805150 1F RST CHIPR 1.5 KOHM +-1% 1/8W R829 061G1206330 RST CHIPR 33 OHM +-5% 1/4W R836 061G0805102 RST CHIPR 1K OHM +-5% 1/8W R837 061G1206220 RST CHIPR 22 OHM +-5% 1/4W R841 061G0805487 0F RST CHIPR 487 OHM +-1% 1/8W R842 061G1206220 RST CHIPR 22 OHM +-5% 1/4W R846 061G0805511 RST CHIPR 510 OHM +-5% 1/8W R847 061G0805105 RST CHIPR 1M OHM +-5% 1/8W R858 061G0805751 RST CHIPR 750 OHM +-5% 1/8W R900 061G1206624 RST CHIPR 620 KOHM +-5% 1/4W R901 061G1206624 RST CHIPR 620 KOHM +-5% 1/4W R902 061G1206624 RST CHIPR 620 KOHM +-5% 1/4W R903 061G1206335 RST CHIPR 3.3M OHM +-5% 1/4W R904 061G1206335 RST CHIPR 3.3M OHM +-5% 1/4W R905 061G1206335 RST CHIPR 3.3M OHM +-5% 1/4W R906 061G0805104 RST CHIPR 100K OHM +-5% 1/8W R908 061G1206203 RST CHIPR 20 KOHM +-5% 1/4W R909 061G152M10452T RST MOFR 100KOHM +-5% 2WS R910 061G1206249 RST CHIPR 2.4 OHM +-5% 1/4W R911 061G1206100 RST CHIPR 10 OHM +-5% 1/4W R912 061G0603100 2F RST CHIPR 10K OHM +-1% 1/10W R913 061G1206221 RST CHIPR 220 OHM +-5% 1/4W R914 061G152M68852T SY RST MOFR 0.68 OHM +-5% 2WS FUTABA R915 061G1206101 RST CHIPR 100 OHM +-5% 1/4W R916 061G1206101 RST CHIPR 100 OHM +-5% 1/4W R917 061G1206101 RST CHIPR 100 OHM +-5% 1/4W http://www.wjel.net   - 33 - R918 061G1206101 RST CHIPR 100 OHM +-5% 1/4W R919 061G1206101 RST CHIPR 100 OHM +-5% 1/4W R920 061G1206101 RST CHIPR 100 OHM +-5% 1/4W R921 061G0805151 RST CHIPR 150 OHM +-5% 1/8W R922 061G0603100 1F RST CHIPR 1 KOHM +-1% 1/10W R923 061G0603100 1F RST CHIPR 1 KOHM +-1% 1/10W R924 061G152M10152T RST MOFR 100OHM +-5% 2WS FUTABA R925 061G0603471 RST CHIPR 470 OHM +-5% 1/10W R926 061G0603100 1F RST CHIPR 1 KOHM +-1% 1/10W R927 061G0805102 RST CHIPR 1K OHM +-5% 1/8W R928 061G0603365 1F RST CHIPR 3.65 KOHM +-1% 1/10W R929 061G0805432 2F RST CHIPR 43.2 KOHM +-1% 1/8W R930 061G0603243 1F RST CHIPR 2.43K OHM +-1% 1/10W TRANSFORMER PT801 080GL17T 40 H XFMR INVERTER DADON PT801 080GL17T 40 DN X'FMR TK.2001U.101 PT801 006G 31502 1.5MM RIVET PT801 S80GL17T40V TRANSFORMER ASS'Y T901 080GL17T 47 S X'FMR 600UH T901 006G 31502 1.5MM RIVET OTHER CN801 033G8021 2E U INVERT CONNECTOR CN802 033G8021 2E U INVERT CONNECTOR CN901 087G 501 32 S AC SOCKET CN901 006G 31500 EYELET CN902 095G 825 9W524 WIRE HARNESS 9P(SCN)-9P(2008)120MM F901 084G 41004 L 877SERIES 4A 250V F901 006G 31502 1.5MM RIVET F902 095G 90 23 JUMPER WIRE F903 095G 90 23 JUMPER WIRE FB901 071G 55 29 FERRITE BEAD HS1 090G6064 1 HEAT SINK J801 095G 90 23 JUMPER WIRE J802 095G 90 23 JUMPER WIRE J803 095G 90 23 JUMPER WIRE J804 095G 90 23 JUMPER WIRE J805 095G 90 23 JUMPER WIRE J806 095G 90 23 JUMPER WIRE J901 095G 90 23 JUMPER WIRE J902 095G 90 23 JUMPER WIRE J903 095G 90 23 JUMPER WIRE J904 095G 90 23 JUMPER WIRE J905 095G 90 23 JUMPER WIRE J906 095G 90 23 JUMPER WIRE J907 095G 90 23 JUMPER WIRE J908 095G 90 23 JUMPER WIRE L901 073G 174 65 H2 LINE FILTER 30MH MIN http://www.wjel.net   - 34 - L901 006G 31502 1.5MM RIVET L903 073G 253191 H IND CHOKE 1.1UH DADON L904 073G 253191 H IND CHOKE 1.1UH DADON http://www.wjel.net   - 35 - DIFFERENT PARTS LIST W1943TB Diversity of T8RANDNBMWLFHN Compared with T8RGNDNBMWLFHN Location Part No. for TPV Description 705GQ934028 REAR COVER/HINGE ASS'Y Q34G0573 B6 3K0100 REAR COVER L185W-9LG 750GLU185X1012N000 PANEL M185XW01 V00 SZ AUO 756GQ8CB KL011 MAIN BOARD-CBPCRNDLGQ1 SMTCR-U402 100GKNA8001N11 MCU ASS'Y-056G1133 81 Q15G0414301 MAINFRAME http://www.wjel.net   - 36 - SCHEMATIC DIAGRAM DVI_5V 5VCC DDC1_SDA 5 DSUB_5V U108 NC / M24C02-WMN6TP 1 2 3 4 5 6 7 8 A0 A1 A2 VSS SDA SCL WP VCC R141 1K 1/16W 5% U103 AZC199-04S 1 2 3 4 5 6 I/O1 GND I/O2 I/O3 VDD I/O4 VGA_B+ R114 100R 1/16W 5% DVI_SCL VGA_R+ RX0N R128 10R 1/16W 5% ESD_5V 5VCC R108 75R 1/16W 5% C103 22pF R104 100R 1/16W 5% VGA_R+ V_Sy nc R126 10R 1/16W 5% R120 1K 1/16W 5% R111 100R 1/16W 5% R109 100R 1/16W 5% U107 AZC199-04S 1 2 3 4 5 6 I/O1 GND I/O2 I/O3 VDD I/O4 ZD104 RLZ5.6B C101 NC RX2P U104 AZC199-04S 1 2 3 4 5 6 I/O1 GND I/O2 I/O3 VDD I/O4 R110 470R 1/16W 5% V_Sy nc DGND VGA_G+ R113 100R 1/16W 5% R150 NC/100R 1/16W 5% R136 4K7 1/16W 5% C102 0.047uF DDC2_SDA U105 AZC199-04S 1 2 3 4 5 6 I/O1 GND I/O2 I/O3 VDD I/O4 GND POWER 5VCC U102 M24C02-RMN6TP 1 2 3 4 5 6 7 8 A0 A1 A2 VSS SDA SCL WP VCC ESD_5V RX1P VGA_G+ RXCN DSUB_SDA R117 100R 1/16W 5% C112 NC R112 75R 1/16W 5% R134 10R 1/16W 5% VGA_R+ R116 75R 1/16W 5% DSUB_SCL C109 5pF/50V ZD105 NC/RLZ5.6B 5V_ESD R142 0 OHM +-5% 1/16W R132 10R 1/16W 5% R127 10R 1/16W 5% C115 0.1UF 16V C117 0.22uF16V R122 100R 1/16W 5% DVI_5V VGA_B+ R107 2K2 1/16W 5% DVI_SDA R133 NC RX0P C106 0.047uF D102 BAV70 3 1 2 R151 NC/4K7 1/16W 5% R115 100R 1/16W 5% RXCP R118 100R 1/16W 5% DVI_5V VGA_G+ R105 100R 1/16W 5% C104 22pF C113 5pF/50V U106 AZC199-04S 1 2 3 4 5 6 I/O1 GND I/O2 I/O3 VDD I/O4 R140 NC 5V_ESD R147 NC/100R 1/16W 5% H_Sy nc R148 NC/4K7 1/16W 5% VGA_B+ H_Sy nc C119 NC VGA_B- R101 100R 1/16W 5% R121100R 1/16W 5% R138 4K7 1/16W 5% R149 NC/4K7 1/16W 5% VGA_B- DSUB_SCL DDC2_SCL FB103 BEAD 1 2 D103 NC/BAT54C 5V_ESD DVI_SCL VGA_G- R106 2K2 1/16W 5% DDC1_SCL 5 FB105 120 OHM 1 2 R143 4K7 1/16W 5% ESD_5V CN101 DB15 1 6 2 7 3 8 4 9 5 11 12 13 14 15 10 17 16 FB102 BEAD 1 2 R137 4K7 1/16W 5% DSUB_SDA C105 5pF/50V R131 10R 1/16W 5% 5VCC R102 0R05 1/10W 5% C121 NC/0.22uF16V C120 NC DSUB_SCL DDC_WP 5 VGA_G- R139 1K 1/16W 5% C111 0.047uF C108 0.047uF R119 100R 1/16W 5% DSUB_SDA C110 0.047uF Q101 NC R144 4K7 1/16W 5% CN102 JACK 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 26 25 DAT2- DAT2+ 2/4shield DAT4- DAT4+ DDC SCL DDC SDA VSYNC DAT1- DAT1+ 1/3shield DAT3- DAT3+ +5V SYNC GND HPD DAT0- DAT0+ 0/5shield DAT5- DAT5+ clk shield clk+ clk- GND GND VGA_PLUG RX2N VGA_R- DSUB_5V RX1N VGA_R- C107 1000pF DSUB_5V FB101 BEAD 1 2 DVI_HPD C114 0.047uF DVI_SDA R103 100R 1/16W 5% R135 NC R129 10R 1/16W 5% R130 10R 1/16W 5% ESD_5V VGA_DET 5 C118 NC 1. SCALER  http://www.wjel.net   - 37 - LED_ORANGE 5 LVB1M TCLK1M 5 RXE0- LVA2P LVA3P C432 NC/0.1UF 16V R438 0R05 1/16W LVA1P RXOC- 2 T7M 5 LVB3P LVA1M RXE3- RXE0+ LVACKP CN402 CONN 1 2 3 4 5 6 7 LED_LF_BLUE 5 LED_GRN/BLUE R305 10K 1/16W 5% LVA3P LVA2M TCLK2M 5 LVA1P LED_ORANGE CN401 NC/CONN 1 2 3 4 5 6 +5V R304 22K 1/16W 5% RXOC- ZD401 NC 1 2 LVA0M R302 220 OHM 1/4W LVB3P D TCLK2P 5 T3M 5 RXO3- LVB1P C431 0.1UF 16V T5P 5 T5M 5 RXO3- LVB0P RXOC+ RXE0+ LVA3M LVA2M +5V G LVB0P R439 0R05 1/16W LVA3M R308 10K 1/16W 5% RXEC- KEY2 CN302 CONN 2 4 6 8 10 12 14 16 18 20 22 24 26 28 30 1 3 5 7 9 11 13 15 17 19 21 23 25 27 29 RXE3+ RXO2- LVB1P LVB2P R306 56K 1/16W 5% T3P 5 LVA1M ZD402 NC 1 2 U301 NC/AO4411 1 2 3 4 8 7 6 5 S S S G D D D D LVB2M C435 0.1UF 16V LVBCKM T6M 5 RXO1- LVB2M RXO2+ RXO1- R445 3.9K OHM 1/16W RXOC+ R437 NC R443 NC/3.9K OHM 1/16W KEY1 5 LVA2P T1M 5 LVA0M RXO2+ 3 KEY2 5 RXE1- C433 NC/0.1UF 16V RXE2+ LVA0P LVBCKM RXE3+ C302 0.22uF16V T2P 5 R307 NC CN403 NC/CONN 2 4 6 8 1 3 5 7 RXE1+ Both CN401 and CN402 foot-print RXO3+ RXEC- RXO0- RXE2- R301 220 OHM 1/4W FB402 NC AO3401L R444 3.9K OHM 1/16W Q302 2N3904S-RTK/PS LVBCKP RXO1+ C304 0.1UF 16V PANEL_VCC RXEC+ T2M 5 T4P 5 + C305 100UF25V RXO0- RXE0- ZD403 NC 1 2 Both CN403,CN404 and CN405 foot-print VCC3.3 RXE1- RXE3- Q301 AO3401 LVA0P FB301 120 OHM 1 2 C303 1uF/16V T7P 5 T6P 5 RXO0+ KEY1 CN405 NC/CONN 1 2 3 4 5 6 7 1 LVB0M CN301 NC 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 TCLK1P 5 RXO0+ RXE2+ RXE2- PPWR_ON# 5 LVACKM R436 NC CN404 NC/CONN 1 2 3 4 5 6 PANEL_VCC RXEC+ T0P 5 T0M 5 LVACKP T4M 5 TOUCH_POWER RXO2- RXO1+ LVB0M C436 NC LVB1M LVACKM T1P 5 LED_LF_BLUE POWER_KEY# 5 POWER_KEY# C434 0.1UF 16V LED_GRN/BLUE 5 LVBCKP LVB3M RXE1+ LVB3M C301 0.1UF 16V RXO3+ S VCC3.3 PANEL_VCC LVB2P R303 4K7 1/16W 5% http://www.wjel.net   - 38 - U701 NC/AP1117E33LA 1 2 3 VSS VOUT VIN BKLT-EN C705 NC/0.1UF 16V VCC3.3 R701 NC/10K 1/16W 5% R702 1K 1/16W 5% R705 1K 1/16W 5% on_BACKLIGHT_5v _1 5 Mute 5 C711 NC/0.1UF 16V C701 NC D702 NC/BAT54C 1 3 2 VCC3.3 U703 AP1117D33L-13 1 2 3 ADJ(GND) VOUT VIN + C707 100UF25V on_BACKLIGHT_1 5 VCC3.3 Both 223 and 252 foot-print C703 NC/0.1UF 16V C712 NC/1uF/16V SOT223 TO252 BKLT-VBRI 5VCC +5V 5VCC 5VCC R711 NC DVI_5V C708 0.1UF 16V FB701 NC/300 OHM 1 2 5VCC +5V E5VCC PANEL_ID# 5 DSUB_5V adj_BACKLIGHT 5 R706 100R 1/16W 5% VCC1.8 C709 0.1UF 16V R710 NC ADD R711 LG 20081029 BKLT-EN + C706 NC/100UF25V Volume# 5 CN701 CONN 1 2 3 4 5 6 7 8 9 U704 NC/AP1117E18LA 3 2 1 4 VI VO GND 4 lock type C710 NC/1N 50V NT60670B OPTION + C704 100UF25V Both 223 and 252 foot-print 5VCC +5V U702 NC/AIC1117A-18PE 1 2 3 ADJ Vout Vin C702 0.1UF 16V BKLT-VBRI R707 NC/4K7 1/16W 5% R708 10K 1/16W 5% Q701 2N3904S-RTK/PS R704 22K 1/16W 5% 5VCC R703 NC/10K 1/16W 5% 20081210: use Pin 123 control BL_ON [on_BACKLIGHT_1]: R446: 0 Ohm; R708: 10K; R704: 22K;R702:1K; Q701:2N3904;C702:0.1uF R447, R711: NC use Pin 39 control BL_ON [on_BACKLIGHT_5V_1]: R447: 0 Ohm; R711: 10K R446,R708,R704,R702,Q701,C702: NC http://www.wjel.net   - 39 - DDC2_SDA 2 T3P 3 R406 NC/10K 1/16W 5% Volume# 4 RX2N 2 DSUB_SOG 2 SPI_SI EE_WP NC/R431 NC/RST CHIP 100R 1/16W 5% R475 NC/2K2 1/16W 5% T5P 3 DVDD KEY1 3 R417 100R 1/16W 5% C412 0.1UF 16V WP R409 100R 1/16W 5% TCLK2P 3 R478 NC/100R 1/10W 5% R416 1K 1/16W 5% R407 20K OHM 1/16W VCC1.8 TCLK2M 3 T7P 3 LED_ORANGE C439 1uF 16V on_BACKLIGHT_5v _1 4 MSCL on_BACKLIGHT_5v C403 1uF 16V C0603 RX1N 2 T0P 3 LED_C C407 0.1UF 16V C438 1uF/16V T0M 3 RX0P 2 NC/R429 NC/100R 1/16W 5% T2M 3 DSUB_G+ 2 FB406 300OHM R454 NC/10K 1/16W 5% LED_GRN/BLUE R441 NC/4K7 1/16W 5% HSO LED_C T7M 3 +5V AVCC ADC_VAA PVCC R425 NC/1K 1/16W 5% DVDD WP VCC3.3 DDC_WP 2 U403 NC/M24C16 1 2 3 4 5 6 7 8 NC NC NC VSS SDA SCL WC VCC +5V adj_BACKLIGHT 4 LED_LF_BLUE 3 C420 22pF AVCC VCC3.3 LED_ORANGE 3 SPI_CE R415 1K 1/16W 5% T5M 3 C423 0.1UF 16V DSUB_R+ 2 R465 2K2 1/16W 5% T6P 3 DSUB_R- 2 on_BACKLIGHT EE_WP Q402 NC/2N3906S-RTK/PS R477 NC/0R05 1/16W +5V DVDD T1M 3 DSUB_V 2 R466 0R05 1/16W R476 NC TX C411 NC/0.22uF16V R413 10K 1/16W 5% VSO BUZZER RX0N 2 POWER_KEY# 3 CN406 NC/CONN 1 2 3 CVDD R471 NC/0R05 1/16W RX2P 2 DDC2_SCL 2 LED_GRN/BLUE 3 R419 10K 1/16W 5% CN407 NC/CONN 1 2 3 4 DVDD TCLK1M 3 DSUB_B- 2 T1P 3 C440 4.7UF 10V C0805 R421 NC/10K 1/16W 5% R420 NC/10K 1/16W 5% C410 0.1UF 16V KEY2 3 C448 1uF 16V C0603 AVCC R412 NC/100R 1/16W 5% VGA_DET 2 SPI_SO SPI_CK R405 10K 1/16W 5% R418 120R 1/16W 5% C446 0.1UF 16V PPWR_ON# 3 R467 NC/0R05 1/16W C406 0.1UF 16V DVDD POWER_KEY# R447 NC/0R05 1/16W FB404 300 OHM X401 12MHz 1 2 LED_A DDC1_SCL 2 T4P 3 DSUB_B+ 2 DSUB_H 2 KEY2 C447 0.1UF 16V DUBUG LED_LF_BLUE FB403 300OHM CVDD FB407 300 OHM ADC_VAA DDC1_SDA 2 SPI_SO SPI_SI LED_A R402 100R 1/16W 5% Q403 NC/2N3906S-RTK/PS U401 NT68667FG/C 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60 61 62 63 64 102 101 100 99 98 97 96 95 94 93 92 91 90 89 88 87 86 85 84 83 82 81 80 79 78 77 76 75 74 73 72 71 70 69 68 67 66 65 128 127 126 125 124 123 122 121 120 119 118 117 116 115 114 113 112 111 110 109 108 107 106 105 104 103 RSTB DVDD DGND RX2+ RX2- AVCC RX1+ RX1- AGND RX0+ RX0- AGND RXC+ RXC- AVCC REXT PVCC PGND BIN1+ BIN1- SOG1I GIN1+ GIN1- RIN1+ RIN1- ADC_VAA ADC_GNDA PC2 PD6 PB3/ADC3/INTE1 P31/TXD P30/RXD PB2/ADC2/INTE0 PB7/DDC_SDA1* PB6/DDC_SCL1* PA3/PWM5 PA4/PWM6* PA5/PWM7* PA6/PWM8* PA7/PWM9* HSYNCI1 VSYNCI1 PLL_GND GND PLL_VDD PB5/DVI_SDA0* PB4/DVI_SCL0* PD5 P35 P34 DVDD CVDD DVDD RSBA1P/V0 RSBA1M/V1 RSBA2P/V2 RSBA2M/V3 RSBA3P/V4 RSBA3M/V5 RSCLKAP/V6 RSCLKAM/V7 RSGA1P/VCKI DGND/CGND DGND/CGND PC6 DGND/CGND DGND/CGND DGND/CGND DGND/CGND DGND/CGND DGND/CGND DGND/CGND DGND/CGND DGND/CGND DGND/CGND DGND/CGND DVDD DGND/CGND RSGB1M/T0M RSGB1P/T0P RSCLKBM/T1M RSCLKBP/T1P RSBB3M/T2M RSBB3P/T2P RSBB2M/TCLK1M RSBB2P/TCLK1P RSBB1M/T3M RSBB1P/T3P DGND/CGND RSRA3M/T4M/RSRB0M RSRA3P/T4P/RSRB0P RSRA2M/T5M/GSGB0M RSRA2P/T5P/RSGB0P RSRA1M/T6M/RSGB0M RSRA1P/T6P/RSBB0P RSGA3M/TCLK2M RSGA3P/TCLK2P RSGA2M/T7M RSGA2P/T7P PA1/PWM3 PA2/PWM4 PA0/PWM2 OSCO OSCI PB0/ADC0 PB1/ADC1 PC5 PC4/PWM1 PC3/PWM0 PC1* PC0* CVDD PWMB*/GPO8 PWMA*/GPO7 NC CVDD INT_HSO/GPO5 INT_VSO/GPO4 GPO3/AD1 GPO2/AD0 NC GND PD4 SPI_CLK SPI_SI SPI_SO SPI_CE PC7 R462 1M 1/16W 5% R470 NC/0R05 1/16W +5V on_BACKLIGHT_1 4 KEY1 VSO PVCC R468 100R 1/10W 5% VCC3.3 T4M 3 MSDA 5V_DET SPI_CK T3M 3 R440 NC/4K7 1/16W 5% For BUZZER control board or Touch Panel VCC3.3 T2P 3 HSO R469 NC/2K2 1/16W 5% R472 NC/100R 1/10W 5% TCLK1P 3 MUTE 4 LED_B MSDA C421 22pF R404 100R 1/16W 5% PANEL_ID# 4 LED_B SPI_CE R446 0R05 1/16W C404 1uF 16V C0603 DSUB_G- 2 C442 0.1UF 16V Q401 2N3906S-RTK/PS RX1P 2 C401 0.22uF16V C422 0.1UF 16V C413 0.1UF 16V R403 10K 1/16W 5% For LED Current, need modify R465/R466/R468/R419 FB401 300 OHM T6M 3 HDCP_CTRL 2 R414 NC C430 0.1UF 16V +5V BUZZER 0402 +5V U402 SST25LF020A-33-4C-SAE 1 2 3 4 5 6 7 8 CE# SO WP# VSS SI SCK HOLD# VDD RXCP 2 R401 470 OHM +-1% 1/16W RXCN 2 DVI_DET 2 MSCL ADD R446,447 LG 20081030 http://www.wjel.net   - 40 - R916 100 OHM 1/4W R924 100OHM 2W R901 620K OHM 1/4W R910 2.4 OHM 1/4W R904 3.3MΩ 1/4W 61G1206335 ! D905 SR5150 1 2 +14.5V L904 1.1uH D906 31DQ06FC3 +5V T901 POWER X'FMR 6 8 5 2 1 11 10 12 9 7 4 GND D903 FR107 U901 LD7577PS 1 2 3 4 5 6 7 8 BNO COMP CS GNDOUT VCC NC HV HS1 HEAT SINK(Q901) 1 2 C912 1500PF2KV R914 0.68 OHM 2W +-5% ZD901 MTZJ T-72 16B 1 2 R906 100K 1/8W 5% 61G0805104 R902 620K OHM 1/4W D901 1N4007 93G 5212T52T ! + C911 47uF/50V R930 2.43K OHM 1% 1/10W ON/OFF R927 1K 1/8W 5% 61G0805102 ! ZD902 RLZ5.6B 93G 39S 24 T 1 2 ZD903 NC NC 1 2 ! ! C916 0.001uF FB901 BEAD 1 2 U902 PC123X2YFZOF 1 2 4 3 ! R911 10R 1/4W 5% CN901 SOCKET 1 2 3 C903 0.47uF ! C900 3300pF 250V - + BD901 KBP208G 2 1 3 4 +5V +5V C906 0.1uF 65G1206104 32 GND + C919 1000UF16V + C905 1uF 450V 67G215S10915T L R908 20K OHM 1/4W J903 JUMPER 1 2 L903 1.1uH R921 150R 1/8W 5% R922 1K 1/10W 1% DIM R912 10K 1/10W 1% ! R905 3.3M OHM 1/14W 61G1206335 + C918 1000UF16V L901 30mH 1 4 2 3 +5V C908 0.01uF R928 3.65K OHM 1% 1/10W ! CN902 Wire Harness 1 2 3 4 5 6 7 8 9 ! R915 100 OHM 1/4W R920 100 OHM 1/4W R926 1K 1/10W 1% F901 FUSE R919 100 OHM 1/4W ON/OFF R929 43.2K OHM 1% 1/8W ! R909 100K OMH 2W +-5% R918 100 OHM 1/4W GND1 GND 1 2 + C917 1000UF25V R917 100 OHM 1/4W C901 1000PF/250VAC D902 FR103 J902 JUMPER 1 2 C914 0.001uF R923 1K 1/10W 1% C904 NC C902 1000PF/250VAC + C907 100UF450V ! C909 470pF + C920 470UF16V R903 3.3MΩ 1/4W 61G1206335 D904 IN4148 ! C921 0.1uF/16V R913 220 OHM 1/4W NR901 NTCR R925 470R 1/10W 5% C913 0.001uF ! U903 KIA431A-AT/P C915 0.1uF/16V DIM R900 620K OHM 1/4W C910 0.1uF/25V Q902 KTD1028 D907 NC Q901 FMA07N65GX 2. POWER http://www.wjel.net   - 41 - C841 0.0039uF/16V R812 10K 1/8W 5% 61G0805103 R826 1K5 1/8W 1% C833 470PF100V 65G060347141J Y C804 1uF/25V 65G0805105 22 R808 47K 1/8W 5% 61G0805473 C839 65G 3J3096ET 3PF/3KV R817 20K OHM 1% 1/8W 61G0805200 2F C837 390pF50V 65G0805391 31 D801 BAV99 93G 64 33 3 1 2 R815 100K 1/8W 5% 61G0805104 FB CN802 CONN 33G8021 2E U 1 2 CT R814 1M 1/8W 5% 61G0805105 +5V D812 1N4148W 93G 6432S CN804 NC 1 2 R809 NC NC PT801 POWER X'FMR 6 3 7 4 1 8 Q806 AO4828L 1 2 3 4 5 6 7 8 S2 G2 S1 G1 D1 D1 D2 D2 R858 750 OHM 1/8W 61G0805751 CN801 CONN 33G8021 2E U 1 2 R811 NC R846 510R 1/8W 5% 61G0805511 R807 22R 1/4W 5% 61G1206220 R825 0 OHM +-5% 1/8W 61G0805000 Y IC801 OZ9938GN 56G 608 10 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 DRV1 VDDA TIMER DIM ISEN VSEN OVPT NC1 NC2 ENA LCT SSTCMP CT GNDA DRV2 PGND R841 61G0805487 0F 487 OHM 1% 1/8W CN803 NC 1 2 R816 1M 1/8W 5% 61G0805105 SST D802 93G 64 33 BAV99 3 1 2 Q812 RK7002 C807 0.01uF 65G0805103 32 R810 1M 1/8W 5% 61G0805105 D806 BAV99 93G 64 33 3 1 2 + C811 470UF25V 67T215P4714AV C805 2200pF50V 65G0805222 31 R842 22R 1/4W 5% 61G1206220 C814 1uF/25V ON/OFF C834 470PF100V 65G060347141J Y C825 12PF6KV 65G 6J1206ET Q811 RK7002 CT R813 1M 1/8W 5% 61G0805105 C803 NC SST C820 0.0039uF/16V 65G0805392 31 C838 0.047uF 65G0805473 32 C809 0.047uF 65G0805473 32 FB C806 1uF/25V 65G0805105 22 R836 1K 1/8W 5% 61G0805102 R837 22R 1/4W 5% 61G1206220 C819 65G0805473 32 0.047uF R847 1M 1/8W 5% 61G0805105 R818 61G1206330 33 OHM 1/4W C828 0.1uF 65G0805104 32 DIM R829 61G1206330 33 OHM 1/4W C813 1000pF 65G0805102 31 C826 3PF/3KV 65G 3J3096ET R819 NC +14.5V C808 180K 1/8W 5% 61G0805184 C810 560PF/50V 65G080556131G 3. INVERTER http://www.wjel.net   - 42 - Mar.2009 P/NO: Printed in China http://www.wjel.net
