LCD TV SERVICE MANUAL CAUTION BEFORE SERVICING THE CHASSIS, READ THE SAFETY PRECAUTIONS IN THIS MANUAL. CHASSIS : LA53A MODEL : 32LX4DC-UB/32LX4DCS-UB website:http://biz.LGservice.com e-mail:http://www.LGEservice.com/techsup.html - 2 - CONTENTS CONTENTS .............................................................................................. 2 PRODUCT SAFETY ..................................................................................3 SPECIFICATION ........................................................................................6 ADJUSTMENT INSTRUCTION................................................................11 TROUBLE SHOOTING............................................................................14 BLOCK DIAGRAM...................................................................................17 EXPLODED VIEW .................................................................................. 18 EXPLODED VIEW PARTS LIST..............................................................19 REPLACEMENT PARTS LIST ............................................................... 20 SVC. SHEET ............................................................................................... - 3 - SAFETY PRECAUTIONS Many electrical and mechanical parts in this chassis have special safety-related characteristics. These parts are identified by in the Schematic Diagram and Replacement Parts List. It is essential that these special safety parts should be replaced with the same components as recommended in this manual to prevent Shock, Fire, or other Hazards. Do not modify the original design without permission of manufacturer. General Guidance An isolation Transformer should always be used during the servicing of a receiver whose chassis is not isolated from the AC power line. Use a transformer of adequate power rating as this protects the technician from accidents resulting in personal injury from electrical shocks. It will also protect the receiver and it's components from being damaged by accidental shorts of the circuitry that may be inadvertently introduced during the service operation. If any fuse (or Fusible Resistor) in this TV receiver is blown, replace it with the specified. When replacing a high wattage resistor (Oxide Metal Film Resistor, over 1W), keep the resistor 10mm away from PCB. Keep wires away from high voltage or high temperature parts. Before returning the receiver to the customer, always perform an AC leakage current check on the exposed metallic parts of the cabinet, such as antennas, terminals, etc., to be sure the set is safe to operate without damage of electrical shock. Leakage Current Cold Check(Antenna Cold Check) With the instrument AC plug removed from AC source, connect an electrical jumper across the two AC plug prongs. Place the AC switch in the on position, connect one lead of ohm-meter to the AC plug prongs tied together and touch other ohm-meter lead in turn to each exposed metallic parts such as antenna terminals, phone jacks, etc. If the exposed metallic part has a return path to the chassis, the measured resistance should be between 1MΩ and 5.2MΩ. When the exposed metal has no return path to the chassis the reading must be infinite. An other abnormality exists that must be corrected before the receiver is returned to the customer. Leakage Current Hot Check (See below Figure) Plug the AC cord directly into the AC outlet. Do not use a line Isolation Transformer during this check. Connect 1.5K/10watt resistor in parallel with a 0.15uF capacitor between a known good earth ground (Water Pipe, Conduit, etc.) and the exposed metallic parts. Measure the AC voltage across the resistor using AC voltmeter with 1000 ohms/volt or more sensitivity. Reverse plug the AC cord into the AC outlet and repeat AC voltage measurements for each exposed metallic part. Any voltage measured must not exceed 0.75 volt RMS which is corresponds to 0.5mA. In case any measurement is out of the limits specified, there is possibility of shock hazard and the set must be checked and repaired before it is returned to the customer. Leakage Current Hot Check circuit 1.5 Kohm/10W To Instrument's exposed METALLIC PARTS Good Earth Ground such as WATER PIPE, CONDUIT etc. AC Volt-meter IMPORTANT SAFETY NOTICE 0.15uF - 4 - CAUTION: Before servicing receivers covered by this service manual and its supplements and addenda, read and follow the SAFETY PRECAUTIONS on page 3 of this publication. NOTE: If unforeseen circumstances create conflict between the following servicing precautions and any of the safety precautions on page 3 of this publication, always follow the safety precautions. Remember: Safety First. General Servicing Precautions 1. Always unplug the receiver AC power cord from the AC power source before; a. Removing or reinstalling any component, circuit board module or any other receiver assembly. b. Disconnecting or reconnecting any receiver electrical plug or other electrical connection. c. Connecting a test substitute in parallel with an electrolytic capacitor in the receiver. CAUTION: A wrong part substitution or incorrect polarity installation of electrolytic capacitors may result in an explosion hazard. 2. Test high voltage only by measuring it with an appropriate high voltage meter or other voltage measuring device (DVM, FETVOM, etc) equipped with a suitable high voltage probe. Do not test high voltage by "drawing an arc". 3. Do not spray chemicals on or near this receiver or any of its assemblies. 4. Unless specified otherwise in this service manual, clean electrical contacts only by applying the following mixture to the contacts with a pipe cleaner, cotton-tipped stick or comparable non-abrasive applicator; 10% (by volume) Acetone and 90% (by volume) isopropyl alcohol (90%-99% strength) CAUTION: This is a flammable mixture. Unless specified otherwise in this service manual, lubrication of contacts in not required. 5. Do not defeat any plug/socket B+ voltage interlocks with which receivers covered by this service manual might be equipped. 6. Do not apply AC power to this instrument and/or any of its electrical assemblies unless all solid-state device heat sinks are correctly installed. 7. Always connect the test receiver ground lead to the receiver chassis ground before connecting the test receiver positive lead. Always remove the test receiver ground lead last. 8. Use with this receiver only the test fixtures specified in this service manual. CAUTION: Do not connect the test fixture ground strap to any heat sink in this receiver. Electrostatically Sensitive (ES) Devices Some semiconductor (solid-state) devices can be damaged easily by static electricity. Such components commonly are called Electrostatically Sensitive (ES) Devices. Examples of typical ES devices are integrated circuits and some field-effect transistors and semiconductor "chip" components. The following techniques should be used to help reduce the incidence of component damage caused by static by static electricity. 1. Immediately before handling any semiconductor component or semiconductor-equipped assembly, drain off any electrostatic charge on your body by touching a known earth ground. Alternatively, obtain and wear a commercially available discharging wrist strap device, which should be removed to prevent potential shock reasons prior to applying power to the unit under test. 2. After removing an electrical assembly equipped with ES devices, place the assembly on a conductive surface such as aluminum foil, to prevent electrostatic charge buildup or exposure of the assembly. 3. Use only a grounded-tip soldering iron to solder or unsolder ES devices. 4. Use only an anti-static type solder removal device. Some solder removal devices not classified as "anti-static" can generate electrical charges sufficient to damage ES devices. 5. Do not use freon-propelled chemicals. These can generate electrical charges sufficient to damage ES devices. 6. Do not remove a replacement ES device from its protective package until immediately before you are ready to install it. (Most replacement ES devices are packaged with leads electrically shorted together by conductive foam, aluminum foil or comparable conductive material). 7. Immediately before removing the protective material from the leads of a replacement ES device, touch the protective material to the chassis or circuit assembly into which the device will be installed. CAUTION: Be sure no power is applied to the chassis or circuit, and observe all other safety precautions. 8. Minimize bodily motions when handling unpackaged replacement ES devices. (Otherwise harmless motion such as the brushing together of your clothes fabric or the lifting of your foot from a carpeted floor can generate static electricity sufficient to damage an ES device.) General Soldering Guidelines 1. Use a grounded-tip, low-wattage soldering iron and appropriate tip size and shape that will maintain tip temperature within the range or 500 F to 600 F. 2. Use an appropriate gauge of RMA resin-core solder composed of 60 parts tin/40 parts lead. 3. Keep the soldering iron tip clean and well tinned. 4. Thoroughly clean the surfaces to be soldered. Use a mall wire- bristle (0.5 inch, or 1.25cm) brush with a metal handle. Do not use freon-propelled spray-on cleaners. 5. Use the following unsoldering technique a. Allow the soldering iron tip to reach normal temperature. (500 F to 600 F) b. Heat the component lead until the solder melts. c. Quickly draw the melted solder with an anti-static, suction- type solder removal device or with solder braid. CAUTION: Work quickly to avoid overheating the circuitboard printed foil. 6. Use the following soldering technique. a. Allow the soldering iron tip to reach a normal temperature (500 F to 600 F) b. First, hold the soldering iron tip and solder the strand against the component lead until the solder melts. c. Quickly move the soldering iron tip to the junction of the component lead and the printed circuit foil, and hold it there only until the solder flows onto and around both the component lead and the foil. CAUTION: Work quickly to avoid overheating the circuit board printed foil. d. Closely inspect the solder area and remove any excess or splashed solder with a small wire-bristle brush. SERVICING PRECAUTIONS - 5 - IC Remove/Replacement Some chassis circuit boards have slotted holes (oblong) through which the IC leads are inserted and then bent flat against the circuit foil. When holes are the slotted type, the following technique should be used to remove and replace the IC. When working with boards using the familiar round hole, use the standard technique as outlined in paragraphs 5 and 6 above. Removal 1. Desolder and straighten each IC lead in one operation by gently prying up on the lead with the soldering iron tip as the solder melts. 2. Draw away the melted solder with an anti-static suction-type solder removal device (or with solder braid) before removing the IC. Replacement 1. Carefully insert the replacement IC in the circuit board. 2. Carefully bend each IC lead against the circuit foil pad and solder it. 3. Clean the soldered areas with a small wire-bristle brush. (It is not necessary to reapply acrylic coating to the areas). "Small-Signal" Discrete Transistor Removal/Replacement 1. Remove the defective transistor by clipping its leads as close as possible to the component body. 2. Bend into a "U" shape the end of each of three leads remaining on the circuit board. 3. Bend into a "U" shape the replacement transistor leads. 4. Connect the replacement transistor leads to the corresponding leads extending from the circuit board and crimp the "U" with long nose pliers to insure metal to metal contact then solder each connection. Power Output, Transistor Device Removal/Replacement 1. Heat and remove all solder from around the transistor leads. 2. Remove the heat sink mounting screw (if so equipped). 3. Carefully remove the transistor from the heat sink of the circuit board. 4. Insert new transistor in the circuit board. 5. Solder each transistor lead, and clip off excess lead. 6. Replace heat sink. Diode Removal/Replacement 1. Remove defective diode by clipping its leads as close as possible to diode body. 2. Bend the two remaining leads perpendicular y to the circuit board. 3. Observing diode polarity, wrap each lead of the new diode around the corresponding lead on the circuit board. 4. Securely crimp each connection and solder it. 5. Inspect (on the circuit board copper side) the solder joints of the two "original" leads. If they are not shiny, reheat them and if necessary, apply additional solder. Fuse and Conventional Resistor Removal/Replacement 1. Clip each fuse or resistor lead at top of the circuit board hollow stake. 2. Securely crimp the leads of replacement component around notch at stake top. 3. Solder the connections. CAUTION: Maintain original spacing between the replaced component and adjacent components and the circuit board to prevent excessive component temperatures. Circuit Board Foil Repair Excessive heat applied to the copper foil of any printed circuit board will weaken the adhesive that bonds the foil to the circuit board causing the foil to separate from or "lift-off" the board. The following guidelines and procedures should be followed whenever this condition is encountered. At IC Connections To repair a defective copper pattern at IC connections use the following procedure to install a jumper wire on the copper pattern side of the circuit board. (Use this technique only on IC connections). 1. Carefully remove the damaged copper pattern with a sharp knife. (Remove only as much copper as absolutely necessary). 2. carefully scratch away the solder resist and acrylic coating (if used) from the end of the remaining copper pattern. 3. Bend a small "U" in one end of a small gauge jumper wire and carefully crimp it around the IC pin. Solder the IC connection. 4. Route the jumper wire along the path of the out-away copper pattern and let it overlap the previously scraped end of the good copper pattern. Solder the overlapped area and clip off any excess jumper wire. At Other Connections Use the following technique to repair the defective copper pattern at connections other than IC Pins. This technique involves the installation of a jumper wire on the component side of the circuit board. 1. Remove the defective copper pattern with a sharp knife. Remove at least 1/4 inch of copper, to ensure that a hazardous condition will not exist if the jumper wire opens. 2. Trace along the copper pattern from both sides of the pattern break and locate the nearest component that is directly connected to the affected copper pattern. 3. Connect insulated 20-gauge jumper wire from the lead of the nearest component on one side of the pattern break to the lead of the nearest component on the other side. Carefully crimp and solder the connections. CAUTION: Be sure the insulated jumper wire is dressed so the it does not touch components or sharp edges. - 6 - 1. Application range This specification is applied to LA53A chassis. 2. Requirement for Test Testing for standard of each part must be followed in below condition. (1) Temperature: 20°C ± 5°C (CST 40°C ± 5°C) (2) Humidity: 65% ± 10% (3) Power: Standard input voltage (AC 100-240V, 50/60Hz) (4) Measurement must be performed after heat-run more than 15min. (5) Adjusting standard for this chassis is followed a special standard. SPECIFICATION NOTE : Specifications and others are subject to change without notice for improvement. 3.General Specification No Item Specification Remark 1. Receiving System ATSC/ 64 & 256 QAM/NTSC-M Slim-VSB 2. Available Channel VHF : 02~13 UHF : 14~69 CATV: 01~135 DTV: 02-69 3. Input Voltage AC 100 ~ 260V 50/60Hz 4. Market North America 5. Screen Size 32 inch wide 6. Aspect Ratio 16:9 7. Tuning System FS 8. LCD Module LC320W01-SL11 (1366x768) LG Philips LCD 9. Operating Environment Temp. : 0 ~ 40 deg Humidity : ~ 80 % 10. Storage Environment Temp. : -20 ~ 50 deg Humidity : 10 ~ 90 % 4. Feature and Function No Item Specification Remark 1. Feature AV Input / Out 2 AV Input1,2(Video, Front Video) Rear1, Rear 1 RGB Input 2 Analog RGB 1, 2 Rear2(D-Sub 15pin) S-Input 2 S-Input Rear1, Front 1 HDMI Input 1 DVI Input Rear1 Y, Pb, Pr Input 2 Component 1, 2 Rear1, Side1 SPDIF Out 1 SPDIF Out Rear SPDIF Input 1 SPDIF Input Rear RS-232C 1 S/W Download D-Sub 9pin, Rear Internal SPK Out 1 Mono, < 2W Rear, for remote speaker 2. Key Local Key POWER, TV/Video, Menu, ENTER, Volume( , ), Channel ( , ), Power (Main) - 7 - No Item Specification Remark 3. SETUP EZ Scan Auto Channel Search CH. Edit CH. Add/Delete DTV Signal Bad/Normal/Good DTV Only Ch. Label Broadcaster. Logo Main Input Antenna, Cable, Video, Front Video, Component, RGB-DTV <-> RGB-PC, RGB-DTV/PC, DVI Input Label VCR, DVD, VCR/DVD, Set top box, Satellite, Cable box Game, PC for Video, Component1/2. RGB, DVI SET ID 1 - 99 4. Picture EZ Picture Custom, Daylight, Normal, Night Time, Movie, Video Game, Sports Contrast / Brightness 0 - 100 Color / Sharpness 0 - 100 Color Temperature Warm/Medium/ Cool Video Preset Factory Preset 5. Audio Audio Language English/Spanish/French DTV Only EZ SoundRite Off/On EZ Sound Custom/Normal/Stadium/News/Theater/Music User Control Balance/Treble/Bass Front Surround Off/3D EchoSound System/SRS TruSurround XT TV Speaker Off/On 6. Time Auto Clock Off/On/, Time Zone/Daylight Saving Manual Clock Year/Data/Time Off Timer Off/On/Time On Timer Off/On/Time/Ch./Vol Sleep Timer Off/10 min/20 min/30 min/60 min/90 min/120 min /180 min/240 min Auto Off Off/On 7. Option Aspect Ratio Set By Program/4:3/16:9/Horizon/Zoom1/ Zoom2/Cinema Zoom(1~16) Caption Off/EZ Mute/On DTV: Horizon disable Caption text CC1/CC2/CC3/CC4/Text1/Text2/Text3/Text4 Caption Option Style/Size/Font/Text Color/Text Opacity/Bg Color/Bg Opacity/Edge Type/Edge Color Language English/Espanol/Francais Cinema 3:2 mode Off/On Demo Ez Demo/XD Demo 8. Lock Lock System Off/On Set Password New/Confirm Block Ch. Select Movie Rating G/PG/PG-13/R/NC-17/X TV Rating-Children Age/Fantasy Violence TV Rating-General Age/Dialogue/Language/Sex/Violence Input.Block Video, Front Video, Component1, RGB, DVI 9. Etc. Comb Filter 3D Comb 3D comb for main display, 4H comb for sub display Remocon LG code - 8 - 5. External Input Format Component Video Input (Y, CB/PB, CR/PR) RGB Iinput (PC/DTV) No Resolution H-freq(kHz) V-freq.(kHz) Pixel clock Proposed 1. 640x480 15.73 60.00 SDTV ,DVD 480I 2. 704x480 31.47 59.94 SDTV 480P 3. 1280x720 45.00 60.00 HDTV 720P 4. 1280x720 44.96 59.94 HDTV 720P 5. 1920x1080 33.75 60.00 HDTV 1080I 6. 1920x1080 33.72 59.94 HDTV 1080I No Resolution H-freq(kHz) V-freq.(kHz) Pixel clock Proposed PC DDC 7. 640x350 31.468 70.09 25.17 EGA O 8. 640x480 31.469 59.94 25.17 VESA(VGA) O 9. 640x480 37.861 72.80 31.50 VESA(VGA) O 10. 640x480 37.500 75.00 31.50 VESA(VGA) O 11. 800x600 35.156 56.25 36.00 VESA(SVGA) O 12. 800x600 37.879 60.31 40.00 VESA(SVGA) O 13. 800x600 48.077 72.18 50.00 VESA(SVGA) O 14. 800x600 46.875 75.00 49.50 VESA(SVGA) O 15. 1024x768 48.363 60.00 65.00 VESA(XGA) O 16. 1024x768 56.476 70.06 75.00 VESA(XGA) O 17. 1024x768 60.023 75.02 78.75 VESA(XGA) O DTV 18. 704x480 31.47 59.94 SDTV 480P 19. 1280x720 45.00 60.00 HDTV 720P 20. 1280x720 44.96 59.94 HDTV 720P 21. 1920x1080 33.75 60.00 HDTV 1080I 22. 1920x1080 33.72 59.94 HDTV 1080I - 9 - DVI Iinput (PC/DTV) No Resolution H-freq(kHz) V-freq.(kHz) Pixel clock Proposed PC DDC 24. 640x350 31.468 70.09 25.17 EGA O 25. 640x480 31.469 59.94 25.17 VESA(VGA) O 26. 640x480 31.861 72.80 31.50 VESA(VGA) O 28. 640x480 37.500 75.00 31.50 VESA(VGA) O 29 800x600 35.156 56.25 36.00 VESA(SVGA) O 30 800x600 48.077 72.18 50.00 VESA(SVGA) O 31 800x600 46.875 75.00 49.50 VESA(SVGA) O 32. 1024x768 48.363 60.00 65.00 VESA(XGA) O 33. 1024x768 56.476 70.06 75.00 VESA(XGA) O 34. 1024x768 60.023 75.02 78.75 VESA(XGA) O DTV 35. 704x480 31.47 59.94 SDTV 480P 36. 1280x720 45.00 60.00 HDTV 720P 37. 1280x720 44.96 59.94 HDTV 720P 38. 1920x1080 33.75 60.00 HDTV 1080I 39. 1920x1080 33.72 59.94 HDTV 1080I 6. POWER No Item Min Typ Max Unit Remark 1. AC Power Operating Voltage 100 240 V 2. DC Voltage, LCD Panel Drive 11.4 12.0 12.6 V 3. DC Voltage, Inverter 22.8 24.0 25.2 V 4. DC Voltage, Sound AMP 18.0 19.0 20.0 V 5. DC Voltage, Stand By 5.6 6.0 6.4 V 6. DC Voltage, Scaler(HD2) 3.1 3.3 3.5 V I/O port supply 7. DC Voltage, Scaler(HD2) 1.6 1.8 1.9 Internal core supply 8. DC Voltage, ADC 3.0 3.3 3.6 V MST3385 DC Voltage, VCD 2.5 V 2.3 2.5 2.7 V 9. DC Voltage, Micom 4.7 5 5.3 V 10. DC Voltage, Tuner 4.75 5.00 5.25 V - 10 - 7. General Specifications No Item Min Typ Max Unit Remark 1 Active Screen Size 750.62(diagonal) mm 29.53 inches 2 Outline Dimension 697.3(H)x431.8(V)x50.9(D) mm 3 Pixel Pitch 0.5025x0.1675xRGB 4 Pixel Format 1280(H)x768(V) stripe arrangement 5 Color Depth 8bit 16.7 Mbit 6 Luminance ,White 500 (center 1 point typ) cd/m2 7 Viewing Angle (CR>10) R/L 176(Typ),U/P 176(Typ) degree 8 Power Consumption 99.16 Watt 9 Weight 6.75 kg 10 Display Operating Mode Transmissive mode ,normally black 11 Surface Treatment Hard coating (3H) 12 Altitude Operating 0 - 14,000 feet 4,267.2 m Storage/Shipment 0 - 40,000 feet 12,192.0 m 8. Electro Optical Characteristic Specifications No Item Min Typ Max Unit Remark 1 Contrast Ratio 600 800 C It measured at center point 2 Surface Luminance, White 400 500 Cd/m2 Full white 3 Luminance Variation 1.3 4 Response Time Tr (Rising time) 16 30 msec 5 Color coordinate RED X 0.632 Full Pattern Y 0.342 GREEN X Typ 0.275 Typ Y -0.03 0.288 +0.03 BLUE X 0.147 Y 0.065 WHITE X 0.287 Y 0.289 6 Viewing Angle X axis right( =0) 85 88 degree (CR>10) X axis left( =180) 85 88 Yaxis up ( =90) 85 88 Z axis down( =270) 85 88 9. Mechanical specification No Item Content Remark 1 Product Width (W) Length (D) Height (H) Dimension 874 109 538 874 186 580.5 With Stand 2 Product Weight 52.2Kg With Stand - 11 - 1. Application Object These instructions are applied to all of the LCD TV, LA53A. 2. Notes (1) Because this is not a hot chassis, it is not necessary to use an isolation transformer. However, the use of isolation transformer will help protect test equipment. (2) Adjustments must be done in the correct order. (3) The adjustments must be performed in the circumstance of 25±5°C of temperature and 65±10% of relative humidity if there is no specific designation. (4) The input voltage of the receiver be must kept 110V, 60Hz when adjusting. (5) The receiver must be operational for about 15 minutes prior to the adjustments. Perform preliminary operation after receiving 100% White Pattern (06CH). (Or 3. White Pattern status of Ez-Adjust) Never press IN-STOP key before shipment. White Pattern entry method A) Enter into Ez-Adjust by pressing the ADJ key on the adjustment R/C. B) 100% FULL WHITE PATTERN appears if pressing the OK ( ) key after selecting the 3.WHITE PATTERN with the CH + / - KEY. * It is possible to heat run the set without a separate signal generator in this mode. Caution : Care must be taken as afterimage phenomena may occur about the black level part of screen If leaving pause image turned on for more than 20 minutes (especially inner digital pattern (13 CH), Cross Hatch Pattern (09CH) with significant black/white contrast). 3. EPLD Download (1) Test Equipment: PC, Jig for download (2) Connect the power of VSC B/D. (3) Execute download program(iMPACK) of PC. (4) After executing the hot key on the Programmer, click icon (5) End after confirming 4. ADC-Set Adjustment 4-1. Synopsis The menu of MST3385A-set let optimum black level and Gain automatically set up during changing from Analog mode to Digital mode and also correct RGB variation. 4-2. Test Equipment Service R/C, MSPG925FA Pattern Generator (720P,480i The Horizontal 100% Color Bar Pattern output will be possible and the output level will accurately have to be revised with 0.7±0.1Vp-p) 4-3. Adjustment (1) ADC MST3385A-720P Adjustment (A) Impress Resolution 720P mode(Model,217) and Pattern 100% Horizontal Color Bar(HozTV31Bar) which follows in the MSPG-925D and then convert to Component mode in input-mode. (B) After receiving signal for at least 1 second, press the ADJ Key on the Service R/C to enter the ‘Ez - Adjust’ and select the ‘1. MST3385A-720P SET’. Pressing the Enter Key to adjust with automatic movement. (C) When the adjustment is over, 'ADC Component 720P Success’ is displayed. (D) If the adjustment has errors, 'ADC Configuration Error’ is displayed. And error massage(‘Component Not Connection’ or ‘Change Format to 480i’ or ‘Check Pattern of device’) is displayed for 1 second. (2) ADC MST3385A-480i Adjustment (A) Impress Resolution 480i mode(Model,217) and Pattern 100% Horizontal Color Bar(HozTV31Bar) which follows in the MSPG-925D and then convert to Component mode in input-mode. (B) After receiving signal for at least 1 second, press the ADJ Key on the Service R/C to enter the ‘Ez - Adjust’ and select the ‘3. MST3385A-480I Success’. Pressing the Enter Key to adjust with automatic movement. (C) When the adjustment is over, 'MST3385 Component Success’ is displayed. If the adjustment has errors, 'MST3385A Configuration Error’ is displayed. ADJUSTMENT INSTRUCTION PC VSC B/D (720P/60Hz : Format No.217, Pattern No. 65) (480i/60Hz : Format No.209, Pattern No. 65) - 12 - (D) Readjust after confirming the case Pattern or adjustment condition where the adjustment errors. (E) After adjustment is complete, exit the adjustment mode by pressing the ADJ KEY. 5. Video(uPD)-Set Adjustment for reduce color difference Main/Sub screen of RF or Video signal. 5-1. Adjustment (1) Connection the Video Signal Generator(Master) to the TV AV Input terminal. After input pattern(Model: 201(NTSC-M), Pattern: 33(100% color Bar), pressing the ‘Rev’ button and appear as below figure (2) After receive signal, confirm the signal receiving. And Enter the ‘EZ-ADJUST’ by pressing the ADJ Key on the Service R/C. Select ‘5. Video(UPD)-Set’ and enter the adjustment mode by pressing the right key (G ). (3) When enter the adjustment mode, displayed the TV 2CH SPLIT Screen automatic at picture and appear as below figure. (4) When the automatic adjustment is over, 'RF Configuration Success’ is displayed. If the adjustment has errors, 'Video Configuration Error’ is displayed. (5) After the RF signal automatic adjustment is over, convert the Video Mode as below figure and adjust with automatic movement the Video Mode. When the automatic adjustment is over, 'Video Configuration Success’ is displayed. If the adjustment has errors, 'Video Configuration Error’ is displayed 6. EDID(The Extended Display Identification Data)/DDC (Display Data Channel) Download This is the function that enables “Plug and Play". - RGB - DVI(128Byte) - DVI(256Byte) - 13 - SVC REMOCON NO KEY FUNTION REAMARK 1 POWER 2 POWER ON 3 MUTE 4 P-CHECK 5 S-CHECK 6 ARC 7 CAPTION 8 TXT 9 TV/AV 10 TURBO SOUND 11 TURBO PICTURE 12 IN-START 13 ADJ 14 MPX 15 EXIT 16 APC(PSM) 17 ASC(SSM) 18 MULTIMIDIA 19 FRONT-AV 20 CH 21 VOL 22 ENTER 23 PIP CH-(OP1) 24 PIP CH+(OP2) 25 PIP SWAP(OP3) 26 PIP INPUT(OP4) 27 EYE 28 MENU 29 IN-STOP 30 STILL 31 TIME 32 SIZE 33 MULTI PIP 34 POSITION 35 MODE 36 PIP 37 TILT 38 0~9 To turn the TV on or off To turn the TV on automatically if the power is supplied to the TV. (Use the POWER key to deactivate): It should be deactivated when delivered. To activate the mute function. To check TV screen image easily. To check TV screen sound easily To select size of the main screen (Normal, Spectacle, Wide or Zoom) Switch to closed caption broadcasting To toggle on/off the teletext mode To select an external input for the TV screen To start turbo sound To start turbo picture To enter adjustment mode when manufacturing the TV sets. To adjust the screen voltage (automatic): In-start mute Adjust AV(Enter into W/B adjustment mode) W/B adjustment (automatic): After adjusting the screen W/B adjustment Exit two times (Adjustment completed) To enter into the adjustment mode. To adjust horizontal line and sub-brightness. To select the multiple sound mode (Mono, Stereo or Foreign language) To release the adjustment mode To easily adjust the screen according to surrounding brightness To easily adjust sound according to the program type To check component input To check the front AV To move channel up/down or to select a function displayed on the screen. To adjust the volume or accurately control a specific function. To set a specific function or complete setting. To move the channel down in the PIP screen. To use as a red key in the teletext mode To move the channel in the PIP screen To use as a green key in the teletext mode To switch between the main and sub screens To use as a yellow key in the teletext mode To select the input status in the PIP screen To use as a blue key in the teletext mode To set a function that will automatically adjust screen status to match the surrounding brightness so natural color can be displayed. To select the functions such as video, voice, function or channel. To set the delivery condition status after manufacturing the TV set. To halt the main screen in the normal mode, or the sub screen at the PIP screen. Used as a hold key in the teletext mode (Page updating is stopped.) Displays the teletext time in the normal mode Enables to select the sub code in the teletext mode Used as the size key in the PIP screen in the normal mode Used as the size key in the teletext mode Used as the index key in the teletext mode (Top index will be displayed if it is the top text.) To select the position of the PIP screen in the normal mode Used as the update key in the teletext mode (Text will be displayed if the current page is updated.) Used as Mode in the teletext mode To select the simultaneous screen To adjust screen tilt To manually select the channel. Shortcut keys Shortcut keys Shortcut keys Use the AV key to enter the screen W/B adjustment mode. Shortcut keys Shortcut keys Shortcut keys - 14 - TROUBLESHOOTING No power Connector connection Replace Power_board Replace Power_board Power On key OK Power supply Check connector connection status. Stand voltage check: D-board P100+5V-STDBY Stand voltage check: A-board P502 #5Pin 5V Check 15V or 5V of Lips Connection of power supply part : Check wiring status of the 13-pin connector Connection of power supply part : Check wiring status of the 15-pin connector Power on signal level : D-board P101 'power0' 3.3V D_board main voltage: P100 '+3.3V', '+6V-P', '12V-P', '+30V-P' Fail Fail Fail Fail Fail Pass Pass Pass Pass Pass Pass Pass Replace Power_board Replace D_board MICOM IC101 - 15 - No Raster Replace Power board Stand by voltage : D_board P100 +12V-P Check No Power (Go to Power) Fail Pass Pass Pass Pass Pass Pass Pass Pass Replace Q202/Q200 Replace D_board Stand by voltage : D_board Q202 #5, #6, #7, #8 12V D_Board P202 LVDS Signal Exist? Check No Power (Go to Power) Fail Fail Fail Fail Replace D_board Replace A_board A_board P502 #13 15V Check No Power (Go to Power) Check Module T-con voltage: D-board P202 #2, #3, #4pin 12V? Replace LCD Module - 16 - No Sound Replace Connector Replace Power Board Replace A_Board Replace Speaker Check Sound supply: A_board P502 #1, #2 18V Power board 15Pin Connector check Fail Fail Fail Pass Pass Pass Speaker output check : Is there waveform of P600/P601 #1? BLOCK DIAGRAM(LCD Built-In) - 17 - - 18 - EXPLODED VIEW 010 150 160 040 170 180 020 060 071 070 080 090 100 110 120 130 030 140 050 - 19 - EXPLODED VIEW PARTS LIST No. PART NO. DESCRIPTION 3091TKE034X Cover Assembly, 32LX4DC-UB LA53A 32" CABINET LGDMX PHANTOM FOR LOCAL ASS'Y 3091TKE034W Cover Assembly, 32LX4DCS-UB LA53A 32" CABINET LGEMX PHANTOM FOR LOCAL ASS'Y EAJ32763001 LCD,Module-TFT, LC320W01-SL18 WXGA 32INCH 1366X768 500CD COLOR 72% 16/9 800:1 A-TW Pol. P6 LG PHILIPS LCD or EAJ30768801 LCD Module, LC320W01-SL14 WXGA 32.0INCH 1366X768 500CD COLOR 72% 16/9 800 NEC Lamp LG PHILIPS LCD . or 6304FLP359A LCD,Module-TFT, LC320W01-SL11 DRIVER 32INCH 1366X768 500CD COLOR 72% 16/9 800:1 - LG PHILIPS LCD 3809900197M Cover Assembly, 32LX4DC/S-UA/UB COMMERCIAL 32" BACK COVER LGEMX PHANTOM FOR LOCAL ASS'Y 3043TKK252R Base Assembly, STAND 32LX4DC-UA/UB LA53A BK LGEMX PHANTOM 3043TKK252S Base Assembly, STAND 32LX4DCS-UA/UB LA53A SILVER LGEMX PHANTOM(LOCAL ASS'Y) 3550TKK938F Cover, MOLD HIPS 51SF 32LX3DC/32LX4DC HIPS 51SF No Spray Set 4951TKS222S Plate Assembly, ASSY 32LX4DC/S-UB MAIN FRAME LGEMX PHANTOM FOR LOCAL ASS'Y 4950TKA210C Plate, PRESS SBHG T1.6 SIDE BRACKET LEFT 32LX1D LPL SL01/05 MODULE 4950TKA210D Plate, PRESS SBHG T1.6 SIDE BRACKET RIGHT 32LX1D LPL SL01/05 MODULE 6871TPT303B PCB Assembly,Power, POWER T.T DU(DCR) COMM - SH(D112) DU/DN/DI-32LP10 BRAND - EBU30789901 Main Total Assembly, 32LX4DC-UA BRAND LA53A - DIGITAL EBR30801401 PCB Assembly, SUB T.T LA53A 32LX4DC-UA ALUSLFX 32LX4DC-UA -SIDE A/V 4951TKK238R Plate Assembly, ASSY 32LX3DC/4DC COMMERCIAL METAL REAR ASSY LGEMX PHANTOM 4815TKK046F Plate Assembly, REAR SHIELD ASSY 32LX3DC CSKD 3551TKK589Z Cover Assembly, 32LX4DC/S-UA/UB LA53A 32" AV BRACKET LGEMX PHANTOM FOR LOCAL ASS'Y 3141TZZ172A Chassis Assembly, CONTROL BOX, 32LP1DC-U, LST-4100A, COMMERCIAL,KIMIN EBR30800701 PCB Assembly, SUB T.T LA53A 32LX4DC-UA ALUSLFX 32LX4DC-UA - CONTROL EBR30800102 PCB Assembly,Front, SUB T.T LA53A 32LX4DC-UA ALUSLFX 32LX4DC-UA - LED EAB30827201 Speaker,Fullrange, C112K01K1450. FERRITE 15W 8OHM 83.5DB 170HZ 116 X 42 X 38.5 LUG 33139D3078A Main Total Assembly, 32LP2DC-UA BRAND LA53A..- ANALOG 010 020 030 040 050 060 070 071 080 090 100 110 120 130 140 150 160 170 180 - 20 - DATE: 2006. 11. 20. *S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION C101 0CE106VF6DC VGV106M016S0ANB010 10uF 20% C102 0CE106VF6DC VGV106M016S0ANB010 10uF 20% C103 0CE106VF6DC VGV106M016S0ANB010 10uF 20% C105 0CE106VF6DC VGV106M016S0ANB010 10uF 20% C203 0CE476VF6DC VGV476M016S0ANE010 47uF 20% C205 0CE226VF6DC VGV226M016S0ANC010 22uF 20% C206 0CE226VF6DC VGV226M016S0ANC010 22uF 20% C210 0CE105SK6DC VMV105M050S0ANB010 1uF 20% C212 0CE105SK6DC VMV105M050S0ANB010 1uF 20% C214 0CE477WF6DC MVK10TP16VC470M 470uF 20% 1 C221 0CE105SK6DC VMV105M050S0ANB010 1uF 20% C222 0CE105SK6DC VMV105M050S0ANB010 1uF 20% C303 0CE476VF6DC VGV476M016S0ANE010 47uF 20% C307 0CE107VF6DC MV6.3TP16VC100M 100uF 20% 1 C321 0CE476VF6DC VGV476M016S0ANE010 47uF 20% C325 0CE106VF6DC VGV106M016S0ANB010 10uF 20% C327 0CE476VF6DC VGV476M016S0ANE010 47uF 20% C338 0CE106VF6DC VGV106M016S0ANB010 10uF 20% C341 0CE106VF6DC VGV106M016S0ANB010 10uF 20% C342 0CE476VF6DC VGV476M016S0ANE010 47uF 20% C344 0CE106VF6DC VGV106M016S0ANB010 10uF 20% C347 0CE476VF6DC VGV476M016S0ANE010 47uF 20% C348 0CE106VF6DC VGV106M016S0ANB010 10uF 20% C349 0CE106VF6DC VGV106M016S0ANB010 10uF 20% C350 0CE106VF6DC VGV106M016S0ANB010 10uF 20% C351 0CE106VF6DC VGV106M016S0ANB010 10uF 20% C353 0CE106VF6DC VGV106M016S0ANB010 10uF 20% C354 0CE106VF6DC VGV106M016S0ANB010 10uF 20% C355 0CE106VF6DC VGV106M016S0ANB010 10uF 20% C356 0CE106VF6DC VGV106M016S0ANB010 10uF 20% C502 0CE476VF6DC VGV476M016S0ANE010 47uF 20% C507 0CE476VF6DC VGV476M016S0ANE010 47uF 20% C510 0CE107VF6DC MV6.3TP16VC100M 100uF 20% 1 C519 0CE335SK6DC VMV335M050S0ANB010 3.3uF 20 C523 0CE226VF6DC VGV226M016S0ANC010 22uF 20% C541 0CE335SK6DC VMV335M050S0ANB010 3.3uF 20 C545 0CE107VF6DC MV6.3TP16VC100M 100uF 20% 1 C546 0CE106VF6DC VGV106M016S0ANB010 10uF 20% C547 0CE106VF6DC VGV106M016S0ANB010 10uF 20% C549 0CE476VF6DC VGV476M016S0ANE010 47uF 20% C551 0CE476VF6DC VGV476M016S0ANE010 47uF 20% C552 0CE475VK6DC VGV475M050S0ANC010 4.7uF 20 C553 0CE475VK6DC VGV475M050S0ANC010 4.7uF 20 C556 0CE107VF6DC MV6.3TP16VC100M 100uF 20% 1 C557 0CE227SF6DC MVG6.3TP16VC220M 220uF 20% C616 0CE476VF6DC VGV476M016S0ANE010 47uF 20% C624 0CE107VF6DC MV6.3TP16VC100M 100uF 20% 1 C652 0CE226VF6DC VGV226M016S0ANC010 22uF 20% C653 0CE226VF6DC VGV226M016S0ANC010 22uF 20% C656 0CE476VF6DC VGV476M016S0ANE010 47uF 20% C658 0CE106VF6DC VGV106M016S0ANB010 10uF 20% C668 0CE226VF6DC VGV226M016S0ANC010 22uF 20% DATE: 2006. 11. 20. *S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION C706 0CE106VF6DC VGV106M016S0ANB010 10uF 20% C708 0CE106VF6DC VGV106M016S0ANB010 10uF 20% C709 0CE106VF6DC VGV106M016S0ANB010 10uF 20% C710 0CE106VF6DC VGV106M016S0ANB010 10uF 20% C713 0CE105SK6DC VMV105M050S0ANB010 1uF 20% C714 0CE105SK6DC VMV105M050S0ANB010 1uF 20% C715 0CE105SK6DC VMV105M050S0ANB010 1uF 20% C716 0CE105SK6DC VMV105M050S0ANB010 1uF 20% C801 0CE476VF6DC VGV476M016S0ANE010 47uF 20% C811 0CE476VF6DC VGV476M016S0ANE010 47uF 20% C900 0CE476VF6DC VGV476M016S0ANE010 47uF 20% C906 0CE106VF6DC VGV106M016S0ANB010 10uF 20% C907 0CH8476F691 MVK6.3TP16VC47M 47uF 20% 16 C912 0CE476VF6DC VGV476M016S0ANE010 47uF 20% C916 0CE476VF6DC VGV476M016S0ANE010 47uF 20% C917 0CE476VF6DC VGV476M016S0ANE010 47uF 20% C934 0CH8106J691 MVK5.0TP35VC10M 10uF 20% 35 C568 0CE4772J618 KMF5.0TP35VB470M 470uF 20% C646 0CE108EJK18 ESM108M035T1G5L20G 1000uF 2 C654 0CE108EJK18 ESM108M035T1G5L20G 1000uF 2 C201 0CH6101K416 C2012C0G1H101JT 100pF 5% 50 C202 0CH6101K416 C2012C0G1H101JT 100pF 5% 50 C207 0CH3103K516 C2012Y5P1H103KT 10nF 10% 50 C216 0CH6101K416 C2012C0G1H101JT 100pF 5% 50 C218 0CH6101K416 C2012C0G1H101JT 100pF 5% 50 C219 0CH2474F566 0805B474K160CT 470nF 10% 16 C223 0CH2474F566 0805B474K160CT 470nF 10% 16 C224 0CH2474F566 0805B474K160CT 470nF 10% 16 C300 0CH6220K416 C2012C0G1H220JT 22pF 5% 50V C301 0CH6220K416 C2012C0G1H220JT 22pF 5% 50V C302 0CH6101K416 C2012C0G1H101JT 100pF 5% 50 C304 0CH3104K566 0805B104K500CT 100nF 10% 50 C305 0CH6101K416 C2012C0G1H101JT 100pF 5% 50 C306 0CH3104K566 0805B104K500CT 100nF 10% 50 C312 0CH2474F566 0805B474K160CT 470nF 10% 16 C313 0CH2474F566 0805B474K160CT 470nF 10% 16 C319 0CH3104K566 0805B104K500CT 100nF 10% 50 C323 0CH2474F566 0805B474K160CT 470nF 10% 16 C324 0CH2474F566 0805B474K160CT 470nF 10% 16 C326 0CH3103K516 C2012Y5P1H103KT 10nF 10% 50 C328 0CK105CD56A C1608X7R1A105KT 1uF 10% 10V C333 0CH3103K516 C2012Y5P1H103KT 10nF 10% 50 C335 0CK472DK56A C2012X7R1H472KT 4.7nF 10% 5 C337 0CH2474F566 0805B474K160CT 470nF 10% 16 C340 0CH3104K566 0805B104K500CT 100nF 10% 50 C352 0CH3104K566 0805B104K500CT 100nF 10% 50 C357 0CH3104K566 0805B104K500CT 100nF 10% 50 C362 0CH2103K516 0805B103K500CT 10nF 10% 50V C363 0CH2103K516 0805B103K500CT 10nF 10% 50V C364 0CH2103K516 0805B103K500CT 10nF 10% 50V C365 0CH2103K516 0805B103K500CT 10nF 10% 50V C500 0CH3103K516 C2012Y5P1H103KT 10nF 10% 50 C503 0CH2152K516 0805B152K500CT 1.5nF 10% 50 C504 0CH3822K516 C2012Y5P1H822KT 8.2nF 10% 5 REPLACEMENT PARTS LIST MAIN BOARD(ANALOG) CAPACITOR For Capacitor & Resistors, the charactors at 2nd and 3rd digit in the P/No. means as follows; CC, CX, CK, CN, CH : Ceramic CQ : Polyestor CE : Electrolytic CF : Fixed Film RD : Carbon Film RS : Metal Oxide Film RN : Metal Film RH : CHIP, Metal Glazed(Chip) RR : Drawing - 21 - DATE: 2006. 11. 20. *S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION C505 0CH3104K566 0805B104K500CT 100nF 10% 50 C506 0CH2152K516 0805B152K500CT 1.5nF 10% 50 C508 0CH3103K516 C2012Y5P1H103KT 10nF 10% 50 C517 0CH5560K416 0805N560J500LT 56pF 5% 50V C518 0CH5560K416 0805N560J500LT 56pF 5% 50V C520 0CH3103K516 C2012Y5P1H103KT 10nF 10% 50 C543 0CH6471K416 C2012C0G1H471JT 470pF 5% 50 C544 0CH3104K566 0805B104K500CT 100nF 10% 50 C548 0CH3104K566 0805B104K500CT 100nF 10% 50 C550 0CH3104K566 0805B104K500CT 100nF 10% 50 C554 0CH3104K566 0805B104K500CT 100nF 10% 50 C555 0CH3104K566 0805B104K500CT 100nF 10% 50 C558 0CH3104K566 0805B104K500CT 100nF 10% 50 C559 0CH3104K566 0805B104K500CT 100nF 10% 50 C560 0CH3104K566 0805B104K500CT 100nF 10% 50 C561 0CH3103K516 C2012Y5P1H103KT 10nF 10% 50 C562 0CH3103K516 C2012Y5P1H103KT 10nF 10% 50 C564 0CH3103K516 C2012Y5P1H103KT 10nF 10% 50 C623 0CH3104K566 0805B104K500CT 100nF 10% 50 C629 0CH3104K566 0805B104K500CT 100nF 10% 50 C631 0CH3104K566 0805B104K500CT 100nF 10% 50 C632 0CH3104K566 0805B104K500CT 100nF 10% 50 C643 0CH3104K566 0805B104K500CT 100nF 10% 50 C645 0CH3103K516 C2012Y5P1H103KT 10nF 10% 50 C647 0CH3104K566 0805B104K500CT 100nF 10% 50 C648 0CH3103K516 C2012Y5P1H103KT 10nF 10% 50 C651 0CH3103K516 C2012Y5P1H103KT 10nF 10% 50 C655 0CH3103K516 C2012Y5P1H103KT 10nF 10% 50 C657 0CH3104K566 0805B104K500CT 100nF 10% 50 C662 0CH3104K566 0805B104K500CT 100nF 10% 50 C663 0CH3104K566 0805B104K500CT 100nF 10% 50 C664 0CH3104K566 0805B104K500CT 100nF 10% 50 C669 0CH3104K566 0805B104K500CT 100nF 10% 50 C700 0CH3104K566 0805B104K500CT 100nF 10% 50 C701 0CH3104K566 0805B104K500CT 100nF 10% 50 C702 0CH3104K566 0805B104K500CT 100nF 10% 50 C707 0CH3104K566 0805B104K500CT 100nF 10% 50 C800 0CH3104K566 0805B104K500CT 100nF 10% 50 C802 0CH3334K946 C2012Y5V1H334ZT 330nF -20TO C803 0CH3104K566 0805B104K500CT 100nF 10% 50 C804 0CH3104K566 0805B104K500CT 100nF 10% 50 C805 0CH3104K566 0805B104K500CT 100nF 10% 50 C808 0CH2103K516 0805B103K500CT 10nF 10% 50V C809 0CH2103K516 0805B103K500CT 10nF 10% 50V C810 0CH2103K516 0805B103K500CT 10nF 10% 50V C812 0CH3104K566 0805B104K500CT 100nF 10% 50 C901 0CH3104K566 0805B104K500CT 100nF 10% 50 C902 0CH3104K566 0805B104K500CT 100nF 10% 50 C903 0CH3104K566 0805B104K500CT 100nF 10% 50 C904 0CH3104K566 0805B104K500CT 100nF 10% 50 C905 0CH3104K566 0805B104K500CT 100nF 10% 50 C908 0CK104CK56A 0603B104K500CT 100nF 10% 50 C909 0CH5102K416 0805N102J500LT 1nF 5% 50V C C910 0CK103CK56A 0603B103K500CT 10nF 10% 50V C911 0CH4101K416 C2012C0G1H101JT 100pF 5% 50 C913 0CK105CD56A C1608X7R1A105KT 1uF 10% 10V C914 0CH3104K566 0805B104K500CT 100nF 10% 50 C915 0CH3104K566 0805B104K500CT 100nF 10% 50 C919 0CH3104K566 0805B104K500CT 100nF 10% 50 C921 0CH3104K566 0805B104K500CT 100nF 10% 50 C922 0CH3104K566 0805B104K500CT 100nF 10% 50 C923 0CH3104K566 0805B104K500CT 100nF 10% 50 DATE: 2006. 11. 20. *S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION C925 0CH3104K566 0805B104K500CT 100nF 10% 50 C100 0CH5150K416 C2012C0G1H150JT 15pF 5% 50V C104 0CH3104K566 0805B104K500CT 100nF 10% 50 C106 0CH5150K416 C2012C0G1H150JT 15pF 5% 50V C200 0CH2474F566 0805B474K160CT 470nF 10% 16 C204 0CH6101K416 C2012C0G1H101JT 100pF 5% 50 C208 0CH6101K416 C2012C0G1H101JT 100pF 5% 50 C209 0CH2474F566 0805B474K160CT 470nF 10% 16 C211 0CH2474F566 0805B474K160CT 470nF 10% 16 C213 0CH3104K566 0805B104K500CT 100nF 10% 50 C215 0CH6101K416 C2012C0G1H101JT 100pF 5% 50 C217 0CH6101K416 C2012C0G1H101JT 100pF 5% 50 C220 0CH3104K566 0805B104K500CT 100nF 10% 50 C308 0CH2474F566 0805B474K160CT 470nF 10% 16 C309 0CH2474F566 0805B474K160CT 470nF 10% 16 C310 0CH2474F566 0805B474K160CT 470nF 10% 16 C311 0CH2474F566 0805B474K160CT 470nF 10% 16 C314 0CH2474F566 0805B474K160CT 470nF 10% 16 C315 0CH2474F566 0805B474K160CT 470nF 10% 16 C316 0CH2474F566 0805B474K160CT 470nF 10% 16 C317 0CH2474F566 0805B474K160CT 470nF 10% 16 C318 0CH2474F566 0805B474K160CT 470nF 10% 16 C320 0CH2474F566 0805B474K160CT 470nF 10% 16 C322 0CH2474F566 0805B474K160CT 470nF 10% 16 C329 0CH2474F566 0805B474K160CT 470nF 10% 16 C330 0CH2474F566 0805B474K160CT 470nF 10% 16 C331 0CH3104K566 0805B104K500CT 100nF 10% 50 C332 0CH2474F566 0805B474K160CT 470nF 10% 16 C334 0CH2474F566 0805B474K160CT 470nF 10% 16 C336 0CH2474F566 0805B474K160CT 470nF 10% 16 C339 0CH5820K416 0805N820J500LT 82pF 5% 50V C343 0CH6101K416 C2012C0G1H101JT 100pF 5% 50 C345 0CH3104K566 0805B104K500CT 100nF 10% 50 C346 0CH3104K566 0805B104K500CT 100nF 10% 50 C360 0CH3104K566 0805B104K500CT 100nF 10% 50 C361 0CH3104K566 0805B104K500CT 100nF 10% 50 C366 0CH2103K516 0805B103K500CT 10nF 10% 50V C367 0CH5471K416 C2012C0G1H471JT 470pF 5% 50 C501 0CH3104K566 0805B104K500CT 100nF 10% 50 C509 0CH3104K566 0805B104K500CT 100nF 10% 50 C511 0CH3104K566 0805B104K500CT 100nF 10% 50 C512 0CH3104K566 0805B104K500CT 100nF 10% 50 C513 0CH3103K516 C2012Y5P1H103KT 10nF 10% 50 C514 0CH3103K516 C2012Y5P1H103KT 10nF 10% 50 C515 0CH5020K116 0805N2R0D500LT 2pF 0.5PF 50 C516 0CH5020K116 0805N2R0D500LT 2pF 0.5PF 50 C521 0CH2474F566 0805B474K160CT 470nF 10% 16 C522 0CK222DK56A CS2012X7R222K500NR 2.2nF 10 C524 0CH2474F566 0805B474K160CT 470nF 10% 16 C525 0CK222DK56A CS2012X7R222K500NR 2.2nF 10 C526 0CH2474F566 0805B474K160CT 470nF 10% 16 C527 0CK222DK56A CS2012X7R222K500NR 2.2nF 10 C528 0CH2474F566 0805B474K160CT 470nF 10% 16 C529 0CH3104K566 0805B104K500CT 100nF 10% 50 C530 0CK222DK56A CS2012X7R222K500NR 2.2nF 10 C531 0CH2474F566 0805B474K160CT 470nF 10% 16 C532 0CK222DK56A CS2012X7R222K500NR 2.2nF 10 C533 0CH2474F566 0805B474K160CT 470nF 10% 16 C534 0CH3103K516 C2012Y5P1H103KT 10nF 10% 50 C535 0CK222DK56A CS2012X7R222K500NR 2.2nF 10 C536 0CH2474F566 0805B474K160CT 470nF 10% 16 C537 0CK222DK56A CS2012X7R222K500NR 2.2nF 10 DATE: 2006. 11. 20. *S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION C538 0CH2474F566 0805B474K160CT 470nF 10% 16 C539 0CK222DK56A CS2012X7R222K500NR 2.2nF 10 C540 0CH3103K516 C2012Y5P1H103KT 10nF 10% 50 C542 0CH6101K416 C2012C0G1H101JT 100pF 5% 50 C567 0CH3104K566 0805B104K500CT 100nF 10% 50 C600 0CK333CK56A C1608X7R1H333KT 33nF 10% 50 C614 0CH3104K566 0805B104K500CT 100nF 10% 50 C619 0CH3334K946 C2012Y5V1H334ZT 330nF -20TO C625 0CH3104K566 0805B104K500CT 100nF 10% 50 C626 0CH3103K516 C2012Y5P1H103KT 10nF 10% 50 C627 0CH2333K516 0805B333K500CT 33nF 10% 50V C628 0CH2333K516 0805B333K500CT 33nF 10% 50V C635 0CH3103K516 C2012Y5P1H103KT 10nF 10% 50 C636 0CH3103K516 C2012Y5P1H103KT 10nF 10% 50 C638 0CH3103K516 C2012Y5P1H103KT 10nF 10% 50 C639 0CH3103K516 C2012Y5P1H103KT 10nF 10% 50 C640 0CH3103K516 C2012Y5P1H103KT 10nF 10% 50 C641 0CH3103K516 C2012Y5P1H103KT 10nF 10% 50 C642 0CH3103K516 C2012Y5P1H103KT 10nF 10% 50 C644 0CH3103K516 C2012Y5P1H103KT 10nF 10% 50 C649 0CH3104K566 0805B104K500CT 100nF 10% 50 C650 0CH3104K566 0805B104K500CT 100nF 10% 50 C667 0CH2333K516 0805B333K500CT 33nF 10% 50V C711 0CH6220K416 C2012C0G1H220JT 22pF 5% 50V C712 0CH6220K416 C2012C0G1H220JT 22pF 5% 50V C806 0CH3104K566 0805B104K500CT 100nF 10% 50 C807 0CH2103K516 0805B103K500CT 10nF 10% 50V C813 0CH6220K416 C2012C0G1H220JT 22pF 5% 50V C929 0CH5102K416 0805N102J500LT 1nF 5% 50V C C930 0CK105CD56A C1608X7R1A105KT 1uF 10% 10V C931 0CH3104K566 0805B104K500CT 100nF 10% 50 C932 0CK105CD56A C1608X7R1A105KT 1uF 10% 10V C933 0CH3104K566 0805B104K500CT 100nF 10% 50 C634 0CF4741L438 PCMT 365 76474 470nF 5% 63V C637 0CF4741L438 PCMT 365 76474 470nF 5% 63V D501 0DS226009AA KDS226 1.2V 85V 300MA 2A 4N D502 0DS226009AA KDS226 1.2V 85V 300MA 2A 4N D600 0DS226009AA KDS226 1.2V 85V 300MA 2A 4N D800 0DS226009AA KDS226 1.2V 85V 300MA 2A 4N D500 0DS226009AA KDS226 1.2V 85V 300MA 2A 4N ZD300 0DZRM00178A UDZS5.1B 5.1V 4.98TO5.2V 80 ZD301 0DZRM00178A UDZS5.1B 5.1V 4.98TO5.2V 80 ZD302 0DZRM00178A UDZS5.1B 5.1V 4.98TO5.2V 80 ZD303 0DZRM00178A UDZS5.1B 5.1V 4.98TO5.2V 80 ZD304 0DZRM00178A UDZS5.1B 5.1V 4.98TO5.2V 80 ZD305 0DZRM00178A UDZS5.1B 5.1V 4.98TO5.2V 80 ZD500 0DZRM00218A UDZS8.2B 8.2V 8.02TO8.36V 3 ZD700 0DZRM00178A UDZS5.1B 5.1V 4.98TO5.2V 80 ZD701 0DZRM00178A UDZS5.1B 5.1V 4.98TO5.2V 80 ZD702 0DZRM00178A UDZS5.1B 5.1V 4.98TO5.2V 80 ZD703 0DZRM00178A UDZS5.1B 5.1V 4.98TO5.2V 80 ZD710 0DZRM00178A UDZS5.1B 5.1V 4.98TO5.2V 80 ZD711 0DZRM00178A UDZS5.1B 5.1V 4.98TO5.2V 80 ZD718 0DZRM00178A UDZS5.1B 5.1V 4.98TO5.2V 80 ZD719 0DZRM00178A UDZS5.1B 5.1V 4.98TO5.2V 80 ZD720 0DZRM00178A UDZS5.1B 5.1V 4.98TO5.2V 80 ZD723 0DZRM00178A UDZS5.1B 5.1V 4.98TO5.2V 80 ZD310 0DZ510009EE UDZS5.1B 5.1V 4.98TO5.2V 80 ZD311 0DZ510009EE UDZS5.1B 5.1V 4.98TO5.2V 80 DATE: 2006. 11. 20. *S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION ZD312 0DZ510009EE UDZS5.1B 5.1V 4.98TO5.2V 80 ZD313 0DZ510009EE UDZS5.1B 5.1V 4.98TO5.2V 80 ZD314 0DZ510009EE UDZS5.1B 5.1V 4.98TO5.2V 80 ZD315 0DZ510009EE UDZS5.1B 5.1V 4.98TO5.2V 80 ZD704 0DZ510009EE UDZS5.1B 5.1V 4.98TO5.2V 80 ZD705 0DZ510009EE UDZS5.1B 5.1V 4.98TO5.2V 80 ZD706 0DZ510009EE UDZS5.1B 5.1V 4.98TO5.2V 80 ZD707 0DZ510009EE UDZS5.1B 5.1V 4.98TO5.2V 80 ZD708 0DZ510009EE UDZS5.1B 5.1V 4.98TO5.2V 80 ZD709 0DZ510009EE UDZS5.1B 5.1V 4.98TO5.2V 80 ZD716 0DZ510009EE UDZS5.1B 5.1V 4.98TO5.2V 80 ZD717 0DZ510009EE UDZS5.1B 5.1V 4.98TO5.2V 80 IC604 0ICB533100A CS5331A-KSR 4.75TO5.25V 48K IC200 0ISO206900A CXA2069Q 8.5TO9.5V - - 1.3W IC100 0IMCRTI007B TPA0242PWPRG4 4.5TO5.5V 0 0 IC603 0IMCRTI028C "TAS5122DCARG4,LF 3TO3.6V_16" IC901 0ILNR00015A NSP-2100A 1.8VTO3.3V - - - IC605 0ISTLTI049A CD4052BPWR 3TO20V 0.1mA MUL IC700 0IMCRTI001A SN74HCT157DR 4.5TO5.5V 0.00 IC300 0IMMRCS013A CAT24C21JI 1KBIT 128X8BIT 2 IC503 0IPRPML001C "MIC39100-2.5WS,LF 2.3TO26V" IC900 0IMCRSJ001A SC1565IST-1.8 2.2TO5.5V 1.8 IC501 0IMCRMN027B MSP4440G-QA-C13-101 7.6TO8. IC301 0IMCRSO025A CXA2181Q 4.75VTO5.25V - 1.6 IC500 0IMCRFA010A KA7809R 11.5TO24V 9V 150W D IC502 0IMCRFA010A KA7809R 11.5TO24V 9V 150W D IC602 0IMCRSH001A PQ05DZ1U 6TO16V 5V 8W D2PAK IC800 0IMCRSH001A PQ05DZ1U 6TO16V 5V 8W D2PAK L606 6140VB0032A DBF-1015A 15.5uH - - 10.8X1 L607 6140VB0032A DBF-1015A 15.5uH - - 10.8X1 L608 6140VB0032A DBF-1015A 15.5uH - - 10.8X1 L609 6140VB0032A DBF-1015A 15.5uH - - 10.8X1 L208 6210TCE001G HH-1M3216-501JT 500OHM 3.2X L300 6210TCE001G HH-1M3216-501JT 500OHM 3.2X L305 6210TCE001G HH-1M3216-501JT 500OHM 3.2X L306 6210TCE001G HH-1M3216-501JT 500OHM 3.2X L511 6210TCE001G HH-1M3216-501JT 500OHM 3.2X L512 6210TCE001G HH-1M3216-501JT 500OHM 3.2X L519 6210TCE001G HH-1M3216-501JT 500OHM 3.2X L702 6210TCE001G HH-1M3216-501JT 500OHM 3.2X L800 6210TCE001G HH-1M3216-501JT 500OHM 3.2X L802 6210TCE001G HH-1M3216-501JT 500OHM 3.2X L804 6210TCE001G HH-1M3216-501JT 500OHM 3.2X L806 6210TCE001G HH-1M3216-501JT 500OHM 3.2X L900 6210TCE001G HH-1M3216-501JT 500OHM 3.2X L901 6210TCE001A HB-1S2012-080JT 8OHM 2X1.25 L902 0LCML00003B MLB-201209-0120P-N2 120OHM L903 0LCML00002B MLB-321611-0050P-N1 50OHM 3 L904 6210TCE001A HB-1S2012-080JT 8OHM 2X1.25 L905 0LCML00003B MLB-201209-0120P-N2 120OHM L906 0LCML00003B MLB-201209-0120P-N2 120OHM L907 6210TCE001G HH-1M3216-501JT 500OHM 3.2X L100 6210TCE001G HH-1M3216-501JT 500OHM 3.2X L200 6210TCE001A HB-1S2012-080JT 8OHM 2X1.25 L201 6210TCE001A HB-1S2012-080JT 8OHM 2X1.25 L202 6210TCE001A HB-1S2012-080JT 8OHM 2X1.25 - 22 - DIODEs IC COIL & CORE & FILTER & INDUCTOR DATE: 2006. 11. 20. *S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION L203 6210TCE001A HB-1S2012-080JT 8OHM 2X1.25 L206 6210TCE001A HB-1S2012-080JT 8OHM 2X1.25 L207 6210TCE001A HB-1S2012-080JT 8OHM 2X1.25 L303 6210TCE001G HH-1M3216-501JT 500OHM 3.2X L500 6210TCE001G HH-1M3216-501JT 500OHM 3.2X L503 6210TCE001G HH-1M3216-501JT 500OHM 3.2X L504 6210TCE001G HH-1M3216-501JT 500OHM 3.2X L509 6210TCE001G HH-1M3216-501JT 500OHM 3.2X L510 6210TCE001G HH-1M3216-501JT 500OHM 3.2X L514 6210TCE001G HH-1M3216-501JT 500OHM 3.2X L515 6210TCE001G HH-1M3216-501JT 500OHM 3.2X L516 6210TCE001G HH-1M3216-501JT 500OHM 3.2X L517 6210TCE001G HH-1M3216-501JT 500OHM 3.2X L518 6210TCE001G HH-1M3216-501JT 500OHM 3.2X L604 6210TCE001G HH-1M3216-501JT 500OHM 3.2X L610 6210TCE001G HH-1M3216-501JT 500OHM 3.2X L616 6210TCE001G HH-1M3216-501JT 500OHM 3.2X L701 6210TCE001G HH-1M3216-501JT 500OHM 3.2X L703 6210TCE001G HH-1M3216-501JT 500OHM 3.2X L803 6210TCE001G HH-1M3216-501JT 500OHM 3.2X L805 6210TCE001G HH-1M3216-501JT 500OHM 3.2X L301 0LC2232101A FI-D3216-223KJT 22UH 10% - L302 0LC2232101A FI-D3216-223KJT 22UH 10% - L304 0LC4732101A FI-B3216-472KJT 4.7UH 10% - L501 0LC1020101A FI-B2012-102KJT 1UH 10% - 1 L502 0LC1020101A FI-B2012-102KJT 1UH 10% - 1 L505 0LC2232101A FI-D3216-223KJT 22UH 10% - L507 0LC2232101A FI-D3216-223KJT 22UH 10% - L700 0LC4732101A FI-B3216-472KJT 4.7UH 10% - L506 0LC2232101A FI-D3216-223KJT 22UH 10% - L508 0LC2232101A FI-D3216-223KJT 22UH 10% - MOS400 0TR830009BA BSS83 N-CHANNEL MOSFET 10V MOS401 0TR830009BA BSS83 N-CHANNEL MOSFET 10V Q206 0TR387500AA 2SC3875S(ALY) NPN 5V 60V 50 Q207 0TR387500AA 2SC3875S(ALY) NPN 5V 60V 50 Q208 0TR387500AA 2SC3875S(ALY) NPN 5V 60V 50 Q209 0TR150400BA 2SA1504S(ASY) PNP -5V -50V Q300 0TR150400BA 2SA1504S(ASY) PNP -5V -50V Q301 0TR150400BA 2SA1504S(ASY) PNP -5V -50V Q306 0TR387500AA 2SC3875S(ALY) NPN 5V 60V 50 Q307 0TR387500AA 2SC3875S(ALY) NPN 5V 60V 50 Q308 0TR387500AA 2SC3875S(ALY) NPN 5V 60V 50 Q309 0TR387500AA 2SC3875S(ALY) NPN 5V 60V 50 Q310 0TR387500AA 2SC3875S(ALY) NPN 5V 60V 50 Q311 0TR387500AA 2SC3875S(ALY) NPN 5V 60V 50 Q500 0TR387500AA 2SC3875S(ALY) NPN 5V 60V 50 Q501 0TR150400BA 2SA1504S(ASY) PNP -5V -50V Q502 0TR150400BA 2SA1504S(ASY) PNP -5V -50V Q503 0TR150400BA 2SA1504S(ASY) PNP -5V -50V Q504 0TR150400BA 2SA1504S(ASY) PNP -5V -50V Q505 0TR387500AA 2SC3875S(ALY) NPN 5V 60V 50 Q506 0TR387500AA 2SC3875S(ALY) NPN 5V 60V 50 Q507 0TR150400BA 2SA1504S(ASY) PNP -5V -50V Q705 0TR387500AA 2SC3875S(ALY) NPN 5V 60V 50 Q706 0TR387500AA 2SC3875S(ALY) NPN 5V 60V 50 Q200 0TR150400BA 2SA1504S(ASY) PNP -5V -50V Q201 0TR387500AA 2SC3875S(ALY) NPN 5V 60V 50 Q202 0TR387500AA 2SC3875S(ALY) NPN 5V 60V 50 Q203 0TR387500AA 2SC3875S(ALY) NPN 5V 60V 50 DATE: 2006. 11. 20. *S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION Q204 0TR387500AA 2SC3875S(ALY) NPN 5V 60V 50 Q205 0TR387500AA 2SC3875S(ALY) NPN 5V 60V 50 Q302 0TR387500AA 2SC3875S(ALY) NPN 5V 60V 50 Q303 0TR387500AA 2SC3875S(ALY) NPN 5V 60V 50 Q304 0TR150400BA 2SA1504S(ASY) PNP -5V -50V Q305 0TR387500AA 2SC3875S(ALY) NPN 5V 60V 50 Q700 0TR387500AA 2SC3875S(ALY) NPN 5V 60V 50 Q701 0TR387500AA 2SC3875S(ALY) NPN 5V 60V 50 Q702 0TR387500AA 2SC3875S(ALY) NPN 5V 60V 50 Q703 0TR150400BA 2SA1504S(ASY) PNP -5V -50V Q704 0TR150400BA 2SA1504S(ASY) PNP -5V -50V Q707 0TR387500AA 2SC3875S(ALY) NPN 5V 60V 50 Q708 0TR387500AA 2SC3875S(ALY) NPN 5V 60V 50 R107 0RH6801D622 MCR10EZHJ682 6.8KOHM 5% 1/8 R200 0RH1001D622 MCR10EZHJ102 1KOHM 5% 1/8W R202 0RH5100D622 MCR10EZHJ511 510OHM 5% 1/8W R205 0RH1501D622 MCR10EZHJ152 1.5KOHM 5% 1/8 R209 0RH1501D622 MCR10EZHJ152 1.5KOHM 5% 1/8 R215 0RH0752D622 MCR10EZHJ750 75OHM 5% 1/8W R217 0RH2200D622 MCR10EZHJ221 220OHM 5% 1/8W R218 0RH5100D622 MCR10EZHJ511 510OHM 5% 1/8W R219 0RH0752D622 MCR10EZHJ750 75OHM 5% 1/8W R220 0RH4702D622 MCR10EZHJ473 47KOHM 5% 1/8W R221 0RH0752D622 MCR10EZHJ750 75OHM 5% 1/8W R222 0RH5100D622 MCR10EZHJ511 510OHM 5% 1/8W R223 0RH3300D622 MCR10EZHJ331 330OHM 5% 1/8W R224 0RH3300D622 MCR10EZHJ331 330OHM 5% 1/8W R225 0RH1000D622 MCR10EZHJ101 100OHM 5% 1/8W R226 0RH1000D622 MCR10EZHJ101 100OHM 5% 1/8W R227 0RH4702D622 MCR10EZHJ473 47KOHM 5% 1/8W R228 0RH4703D622 MCR10EZHJ474 470KOHM 5% 1/8 R230 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 R231 0RH1001D622 MCR10EZHJ102 1KOHM 5% 1/8W R234 0RH2200D622 MCR10EZHJ221 220OHM 5% 1/8W R236 0RH2200D622 MCR10EZHJ221 220OHM 5% 1/8W R237 0RH0752D622 MCR10EZHJ750 75OHM 5% 1/8W R238 0RH0752D622 MCR10EZHJ750 75OHM 5% 1/8W R239 0RH0752D622 MCR10EZHJ750 75OHM 5% 1/8W R241 0RH5100D622 MCR10EZHJ511 510OHM 5% 1/8W R242 0RH5100D622 MCR10EZHJ511 510OHM 5% 1/8W R243 0RH5100D622 MCR10EZHJ511 510OHM 5% 1/8W R300 0RH0822D622 MCR10EZHJ820 82OHM 5% 1/8W R301 0RH0222D622 MCR10EZHJ220 22OHM 5% 1/8W R302 0RH0822D622 MCR10EZHJ820 82OHM 5% 1/8W R303 0RH0222D622 MCR10EZHJ220 22OHM 5% 1/8W R304 0RH7500D622 MCR10EZHJ751 750OHM 5% 1/8W R305 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 R306 0RH0222D622 MCR10EZHJ220 22OHM 5% 1/8W R307 0RH0822D622 MCR10EZHJ820 82OHM 5% 1/8W R308 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 R309 0RH1202D622 MCR10EZHJ123 12KOHM 5% 1/8W R310 0RH1000D622 MCR10EZHJ101 100OHM 5% 1/8W R312 0RH4701D622 MCR10EZHJ472 4.7KOHM 5% 1/8 R314 0RH1000D622 MCR10EZHJ101 100OHM 5% 1/8W R316 0RH2200D622 MCR10EZHJ221 220OHM 5% 1/8W R320 0RH4700D622 MCR10EZHJ471 470OHM 5% 1/8W R322 0RH1501D622 MCR10EZHJ152 1.5KOHM 5% 1/8 R323 0RH2200D622 MCR10EZHJ221 220OHM 5% 1/8W R332 0RH0752D622 MCR10EZHJ750 75OHM 5% 1/8W - 23 - TRANSISTOR RESISTORs DATE: 2006. 11. 20. *S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION R333 0RH0752D622 MCR10EZHJ750 75OHM 5% 1/8W R335 0RH1001D622 MCR10EZHJ102 1KOHM 5% 1/8W R340 0RH0752D622 MCR10EZHJ750 75OHM 5% 1/8W R341 0RH0752D622 MCR10EZHJ750 75OHM 5% 1/8W R345 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 R351 0RH4703D622 MCR10EZHJ474 470KOHM 5% 1/8 R354 0RH1502D622 MCR10EZHJ153 15KOHM 5% 1/8W R360 0RH1000D622 MCR10EZHJ101 100OHM 5% 1/8W R361 0RH1000D622 MCR10EZHJ101 100OHM 5% 1/8W R364 0RH0752D622 MCR10EZHJ750 75OHM 5% 1/8W R365 0RH0752D622 MCR10EZHJ750 75OHM 5% 1/8W R368 0RH0752D622 MCR10EZHJ750 75OHM 5% 1/8W R369 0RH0752D622 MCR10EZHJ750 75OHM 5% 1/8W R370 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 R371 0RH0752D622 MCR10EZHJ750 75OHM 5% 1/8W R375 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 R376 0RH4703D622 MCR10EZHJ474 470KOHM 5% 1/8 R377 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 R380 0RH1502D622 MCR10EZHJ153 15KOHM 5% 1/8W R381 0RH6801D622 MCR10EZHJ682 6.8KOHM 5% 1/8 R382 0RH1001D622 MCR10EZHJ102 1KOHM 5% 1/8W R384 0RH1502D622 MCR10EZHJ153 15KOHM 5% 1/8W R386 0RH6801D622 MCR10EZHJ682 6.8KOHM 5% 1/8 R387 0RH1001D622 MCR10EZHJ102 1KOHM 5% 1/8W R389 0RH1502D622 MCR10EZHJ153 15KOHM 5% 1/8W R390 0RH6801D622 MCR10EZHJ682 6.8KOHM 5% 1/8 R392 0RH1001D622 MCR10EZHJ102 1KOHM 5% 1/8W R394 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 R398 0RH1502D622 MCR10EZHJ153 15KOHM 5% 1/8W R400 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 R401 0RH6801D622 MCR10EZHJ682 6.8KOHM 5% 1/8 R403 0RH1001D622 MCR10EZHJ102 1KOHM 5% 1/8W R404 0RH1502D622 MCR10EZHJ153 15KOHM 5% 1/8W R406 0RH6801D622 MCR10EZHJ682 6.8KOHM 5% 1/8 R408 0RH1001D622 MCR10EZHJ102 1KOHM 5% 1/8W R409 0RH1502D622 MCR10EZHJ153 15KOHM 5% 1/8W R411 0RH6801D622 MCR10EZHJ682 6.8KOHM 5% 1/8 R413 0RH1001D622 MCR10EZHJ102 1KOHM 5% 1/8W R420 0RH1000D622 MCR10EZHJ101 100OHM 5% 1/8W R421 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 R422 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 R433 0RH4702D622 MCR10EZHJ473 47KOHM 5% 1/8W R434 0RH4702D622 MCR10EZHJ473 47KOHM 5% 1/8W R435 0RJ0332D677 MCR03EZPJ330 33OHM 5% 1/10W R436 0RJ0332D677 MCR03EZPJ330 33OHM 5% 1/10W R500 0RH3300D622 MCR10EZHJ331 330OHM 5% 1/8W R501 0RH1202D622 MCR10EZHJ123 12KOHM 5% 1/8W R502 0RH3901D622 MCR10EZHJ392 3.9KOHM 5% 1/8 R503 0RH4700D622 MCR10EZHJ471 470OHM 5% 1/8W R504 0RH1000D622 MCR10EZHJ101 100OHM 5% 1/8W R505 0RH0432D622 MCR10EZHJ430 43OHM 5% 1/8W R506 0RH0432D622 MCR10EZHJ430 43OHM 5% 1/8W R508 0RH1000D622 MCR10EZHJ101 100OHM 5% 1/8W R521 0RH1000D622 MCR10EZHJ101 100OHM 5% 1/8W R527 0RH2200D622 MCR10EZHJ221 220OHM 5% 1/8W R528 0RH2200D622 MCR10EZHJ221 220OHM 5% 1/8W R529 0RH2200D622 MCR10EZHJ221 220OHM 5% 1/8W R530 0RH2200D622 MCR10EZHJ221 220OHM 5% 1/8W R531 0RH1001D622 MCR10EZHJ102 1KOHM 5% 1/8W R532 0RH1001D622 MCR10EZHJ102 1KOHM 5% 1/8W R533 0RH1001D622 MCR10EZHJ102 1KOHM 5% 1/8W R534 0RH1001D622 MCR10EZHJ102 1KOHM 5% 1/8W DATE: 2006. 11. 20. *S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION R535 0RH2201D622 MCR10EZHJ222 2.2KOHM 5% 1/8 R536 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 R537 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 R538 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 R539 0RH1001D622 MCR10EZHJ102 1KOHM 5% 1/8W R540 0RH1501D622 MCR10EZHJ152 1.5KOHM 5% 1/8 R541 0RH2001D622 MCR10EZHJ202 2KOHM 5% 1/8W R542 0RH2001D622 MCR10EZHJ202 2KOHM 5% 1/8W R543 0RH4703D622 MCR10EZHJ474 470KOHM 5% 1/8 R544 0RH1501D622 MCR10EZHJ152 1.5KOHM 5% 1/8 R546 0RH0222D622 MCR10EZHJ220 22OHM 5% 1/8W R554 0RH4703D622 MCR10EZHJ474 470KOHM 5% 1/8 R555 0RH1001D622 MCR10EZHJ102 1KOHM 5% 1/8W R556 0RH1001D622 MCR10EZHJ102 1KOHM 5% 1/8W R600 0RH0101D622 MCR10EZHJ1R0 1OHM 5% 1/8W 2 R602 0RH0101D622 MCR10EZHJ1R0 1OHM 5% 1/8W 2 R603 0RH0101D622 MCR10EZHJ1R0 1OHM 5% 1/8W 2 R604 0RH0101D622 MCR10EZHJ1R0 1OHM 5% 1/8W 2 R634 0RH0101D622 MCR10EZHJ1R0 1OHM 5% 1/8W 2 R635 0RH0101D622 MCR10EZHJ1R0 1OHM 5% 1/8W 2 R638 0RH0101D622 MCR10EZHJ1R0 1OHM 5% 1/8W 2 R639 0RH0101D622 MCR10EZHJ1R0 1OHM 5% 1/8W 2 R640 0RH1500D622 MCR10EZHJ151 150OHM 5% 1/8W R641 0RH1500D622 MCR10EZHJ151 150OHM 5% 1/8W R646 0RH0222D622 MCR10EZHJ220 22OHM 5% 1/8W R648 0RH0222D622 MCR10EZHJ220 22OHM 5% 1/8W R650 0RH0222D622 MCR10EZHJ220 22OHM 5% 1/8W R651 0RH0222D622 MCR10EZHJ220 22OHM 5% 1/8W R659 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 R667 0RH0331D622 MCR10EZHJ3R3 3.3OHM 5% 1/8W R668 0RH0331D622 MCR10EZHJ3R3 3.3OHM 5% 1/8W R705 0RH0222D622 MCR10EZHJ220 22OHM 5% 1/8W R708 0RH0222D622 MCR10EZHJ220 22OHM 5% 1/8W R710 0RH4701D622 MCR10EZHJ472 4.7KOHM 5% 1/8 R713 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 R714 0RH1000D622 MCR10EZHJ101 100OHM 5% 1/8W R738 0RH1001D622 MCR10EZHJ102 1KOHM 5% 1/8W R739 0RH1502D622 MCR10EZHJ153 15KOHM 5% 1/8W R740 0RH1002D622 MCR10EZHJ103 10KOHM 5% 1/8W R741 0RH1001D622 MCR10EZHJ102 1KOHM 5% 1/8W R743 0RH1502D622 MCR10EZHJ153 15KOHM 5% 1/8W R744 0RH1002D622 MCR10EZHJ103 10KOHM 5% 1/8W R745 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 R746 0RH4703D622 MCR10EZHJ474 470KOHM 5% 1/8 R747 0RH1000D622 MCR10EZHJ101 100OHM 5% 1/8W R748 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 R749 0RH4703D622 MCR10EZHJ474 470KOHM 5% 1/8 R755 0RH1502D622 MCR10EZHJ153 15KOHM 5% 1/8W R756 0RH1002D622 MCR10EZHJ103 10KOHM 5% 1/8W R759 0RH1000D622 MCR10EZHJ101 100OHM 5% 1/8W R760 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 R761 0RH4703D622 MCR10EZHJ474 470KOHM 5% 1/8 R764 0RH0752D622 MCR10EZHJ750 75OHM 5% 1/8W R765 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 R766 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 R767 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 R768 0RH0752D622 MCR10EZHJ750 75OHM 5% 1/8W R769 0RH4703D622 MCR10EZHJ474 470KOHM 5% 1/8 R770 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 R771 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 R772 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 R773 0RH4703D622 MCR10EZHJ474 470KOHM 5% 1/8 - 24 - DATE: 2006. 11. 20. *S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION R774 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 R775 0RH0752D622 MCR10EZHJ750 75OHM 5% 1/8W R778 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 R779 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 R800 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 R900 0RH4701D622 MCR10EZHJ472 4.7KOHM 5% 1/8 R905 0RH3301D622 MCR10EZHJ332 3.3KOHM 5% 1/8 R906 0RH0102D622 MCR10EZHJ100 10OHM 5% 1/8W R907 0RH1000D622 MCR10EZHJ101 100OHM 5% 1/8W R909 0RH0222D622 MCR10EZHJ220 22OHM 5% 1/8W R910 0RH0222D622 MCR10EZHJ220 22OHM 5% 1/8W R912 0RH1002D622 MCR10EZHJ103 10KOHM 5% 1/8W R927 0RH4701D622 MCR10EZHJ472 4.7KOHM 5% 1/8 R928 0RH1001D622 MCR10EZHJ102 1KOHM 5% 1/8W R929 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 R100 0RH1001D622 MCR10EZHJ102 1KOHM 5% 1/8W R101 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 R102 0RH1001D622 MCR10EZHJ102 1KOHM 5% 1/8W R103 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 R104 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 R105 0RH1001D622 MCR10EZHJ102 1KOHM 5% 1/8W R106 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 R110 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 R201 0RH0752D622 MCR10EZHJ750 75OHM 5% 1/8W R203 0RH5100D622 MCR10EZHJ511 510OHM 5% 1/8W R204 0RH3301D622 MCR10EZHJ332 3.3KOHM 5% 1/8 R206 0RH2200D622 MCR10EZHJ221 220OHM 5% 1/8W R207 0RH2200D622 MCR10EZHJ221 220OHM 5% 1/8W R208 0RH0752D622 MCR10EZHJ750 75OHM 5% 1/8W R210 0RH0752D622 MCR10EZHJ750 75OHM 5% 1/8W R211 0RH2200D622 MCR10EZHJ221 220OHM 5% 1/8W R212 0RH5601D622 MCR10EZHJ562 5.6KOHM 5% 1/8 R213 0RH2200D622 MCR10EZHJ221 220OHM 5% 1/8W R214 0RH5601D622 MCR10EZHJ562 5.6KOHM 5% 1/8 R216 0RH2200D622 MCR10EZHJ221 220OHM 5% 1/8W R232 0RH2200D622 MCR10EZHJ221 220OHM 5% 1/8W R233 0RH5601D622 MCR10EZHJ562 5.6KOHM 5% 1/8 R235 0RH5601D622 MCR10EZHJ562 5.6KOHM 5% 1/8 R240 0RH5100D622 MCR10EZHJ511 510OHM 5% 1/8W R313 0RH1002D622 MCR10EZHJ103 10KOHM 5% 1/8W R315 0RH1002D622 MCR10EZHJ103 10KOHM 5% 1/8W R317 0RH4701D622 MCR10EZHJ472 4.7KOHM 5% 1/8 R318 0RH1000D622 MCR10EZHJ101 100OHM 5% 1/8W R319 0RH1000D622 MCR10EZHJ101 100OHM 5% 1/8W R321 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 R324 0RH0822D622 MCR10EZHJ820 82OHM 5% 1/8W R325 0RH0822D622 MCR10EZHJ820 82OHM 5% 1/8W R326 0RH0822D622 MCR10EZHJ820 82OHM 5% 1/8W R327 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 R328 0RH0822D622 MCR10EZHJ820 82OHM 5% 1/8W R329 0RH0822D622 MCR10EZHJ820 82OHM 5% 1/8W R330 0RH0822D622 MCR10EZHJ820 82OHM 5% 1/8W R331 0RH0822D622 MCR10EZHJ820 82OHM 5% 1/8W R334 0RH0822D622 MCR10EZHJ820 82OHM 5% 1/8W R336 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 R338 0RH0822D622 MCR10EZHJ820 82OHM 5% 1/8W R339 0RH0822D622 MCR10EZHJ820 82OHM 5% 1/8W R342 0RH1502D622 MCR10EZHJ153 15KOHM 5% 1/8W R343 0RH6801D622 MCR10EZHJ682 6.8KOHM 5% 1/8 R344 0RH0752D622 MCR10EZHJ750 75OHM 5% 1/8W R346 0RH0752D622 MCR10EZHJ750 75OHM 5% 1/8W R347 0RH1001D622 MCR10EZHJ102 1KOHM 5% 1/8W DATE: 2006. 11. 20. *S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION R348 0RH0822D622 MCR10EZHJ820 82OHM 5% 1/8W R350 0RH0822D622 MCR10EZHJ820 82OHM 5% 1/8W R352 0RH1000D622 MCR10EZHJ101 100OHM 5% 1/8W R353 0RH0822D622 MCR10EZHJ820 82OHM 5% 1/8W R355 0RH1502D622 MCR10EZHJ153 15KOHM 5% 1/8W R356 0RH5600D622 MCR10EZHJ561 560OHM 5% 1/8W R357 0RH6801D622 MCR10EZHJ682 6.8KOHM 5% 1/8 R358 0RH1001D622 MCR10EZHJ102 1KOHM 5% 1/8W R359 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 R362 0RH1502D622 MCR10EZHJ153 15KOHM 5% 1/8W R363 0RH4703D622 MCR10EZHJ474 470KOHM 5% 1/8 R366 0RH4700D622 MCR10EZHJ471 470OHM 5% 1/8W R367 0RH6801D622 MCR10EZHJ682 6.8KOHM 5% 1/8 R372 0RH1001D622 MCR10EZHJ102 1KOHM 5% 1/8W R378 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 R379 0RH4703D622 MCR10EZHJ474 470KOHM 5% 1/8 R383 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 R385 0RH0822D622 MCR10EZHJ820 82OHM 5% 1/8W R388 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 R391 0RH0822D622 MCR10EZHJ820 82OHM 5% 1/8W R393 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 R395 0RH0822D622 MCR10EZHJ820 82OHM 5% 1/8W R399 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 R402 0RH0822D622 MCR10EZHJ820 82OHM 5% 1/8W R405 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 R407 0RH0822D622 MCR10EZHJ820 82OHM 5% 1/8W R410 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 R412 0RH0822D622 MCR10EZHJ820 82OHM 5% 1/8W R414 0RH0331D622 MCR10EZHJ3R3 3.3OHM 5% 1/8W R415 0RH0331D622 MCR10EZHJ3R3 3.3OHM 5% 1/8W R416 0RH0331D622 MCR10EZHJ3R3 3.3OHM 5% 1/8W R417 0RH0331D622 MCR10EZHJ3R3 3.3OHM 5% 1/8W R418 0RH0331D622 MCR10EZHJ3R3 3.3OHM 5% 1/8W R419 0RH0331D622 MCR10EZHJ3R3 3.3OHM 5% 1/8W R430 0RJ2201D677 MCR03EZPJ222 2.2KOHM 5% 1/1 R431 0RH1002D622 MCR10EZHJ103 10KOHM 5% 1/8W R432 0RH1002D622 MCR10EZHJ103 10KOHM 5% 1/8W R437 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 R438 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 R509 0RH1000D622 MCR10EZHJ101 100OHM 5% 1/8W R510 0RH1000D622 MCR10EZHJ101 100OHM 5% 1/8W R511 0RH2200D622 MCR10EZHJ221 220OHM 5% 1/8W R512 0RH2200D622 MCR10EZHJ221 220OHM 5% 1/8W R513 0RH2200D622 MCR10EZHJ221 220OHM 5% 1/8W R515 0RH1001D622 MCR10EZHJ102 1KOHM 5% 1/8W R516 0RH1001D622 MCR10EZHJ102 1KOHM 5% 1/8W R517 0RH1001D622 MCR10EZHJ102 1KOHM 5% 1/8W R518 0RH1001D622 MCR10EZHJ102 1KOHM 5% 1/8W R519 0RH1001D622 MCR10EZHJ102 1KOHM 5% 1/8W R520 0RH1001D622 MCR10EZHJ102 1KOHM 5% 1/8W R522 0RH1001D622 MCR10EZHJ102 1KOHM 5% 1/8W R523 0RH1001D622 MCR10EZHJ102 1KOHM 5% 1/8W R524 0RH2200D622 MCR10EZHJ221 220OHM 5% 1/8W R525 0RH2200D622 MCR10EZHJ221 220OHM 5% 1/8W R526 0RH2200D622 MCR10EZHJ221 220OHM 5% 1/8W R601 0RH0101D622 MCR10EZHJ1R0 1OHM 5% 1/8W 2 R605 0RH0101D622 MCR10EZHJ1R0 1OHM 5% 1/8W 2 R606 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 R607 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 R608 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 R609 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 R621 0RH0101D622 MCR10EZHJ1R0 1OHM 5% 1/8W 2 - 25 - DATE: 2006. 11. 20. *S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION R622 0RH0101D622 MCR10EZHJ1R0 1OHM 5% 1/8W 2 R627 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 R628 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 R629 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 R630 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 R631 0RH1002D622 MCR10EZHJ103 10KOHM 5% 1/8W R632 0RH1002D622 MCR10EZHJ103 10KOHM 5% 1/8W R633 0RH4702D622 MCR10EZHJ473 47KOHM 5% 1/8W R636 0RH1002D622 MCR10EZHJ103 10KOHM 5% 1/8W R637 0RH1002D622 MCR10EZHJ103 10KOHM 5% 1/8W R644 0RH0222D622 MCR10EZHJ220 22OHM 5% 1/8W R647 0RH0222D622 MCR10EZHJ220 22OHM 5% 1/8W R649 0RH0222D622 MCR10EZHJ220 22OHM 5% 1/8W R652 0RH0222D622 MCR10EZHJ220 22OHM 5% 1/8W R653 0RH0222D622 MCR10EZHJ220 22OHM 5% 1/8W R666 0RH0101D622 MCR10EZHJ1R0 1OHM 5% 1/8W 2 R701 0RH0222D622 MCR10EZHJ220 22OHM 5% 1/8W R702 0RH0222D622 MCR10EZHJ220 22OHM 5% 1/8W R703 0RH0222D622 MCR10EZHJ220 22OHM 5% 1/8W R704 0RH0222D622 MCR10EZHJ220 22OHM 5% 1/8W R706 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 R707 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 R709 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 R711 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 R715 0RH1001D622 MCR10EZHJ102 1KOHM 5% 1/8W R716 0RH1502D622 MCR10EZHJ153 15KOHM 5% 1/8W R717 0RH1002D622 MCR10EZHJ103 10KOHM 5% 1/8W R718 0RH1001D622 MCR10EZHJ102 1KOHM 5% 1/8W R719 0RH1502D622 MCR10EZHJ153 15KOHM 5% 1/8W R720 0RH1002D622 MCR10EZHJ103 10KOHM 5% 1/8W R721 0RH1001D622 MCR10EZHJ102 1KOHM 5% 1/8W R722 0RH1502D622 MCR10EZHJ153 15KOHM 5% 1/8W R723 0RH1002D622 MCR10EZHJ103 10KOHM 5% 1/8W R724 0RH0822D622 MCR10EZHJ820 82OHM 5% 1/8W R725 0RH0222D622 MCR10EZHJ220 22OHM 5% 1/8W R726 0RH4700D622 MCR10EZHJ471 470OHM 5% 1/8W R727 0RH1001D622 MCR10EZHJ102 1KOHM 5% 1/8W R728 0RH0822D622 MCR10EZHJ820 82OHM 5% 1/8W R729 0RH0222D622 MCR10EZHJ220 22OHM 5% 1/8W R730 0RH0822D622 MCR10EZHJ820 82OHM 5% 1/8W R731 0RH0222D622 MCR10EZHJ220 22OHM 5% 1/8W R732 0RH7500D622 MCR10EZHJ751 750OHM 5% 1/8W R733 0RH2200D622 MCR10EZHJ221 220OHM 5% 1/8W R734 0RH1202D622 MCR10EZHJ123 12KOHM 5% 1/8W R735 0RH2200D622 MCR10EZHJ221 220OHM 5% 1/8W R737 0RH1501D622 MCR10EZHJ152 1.5KOHM 5% 1/8 R742 0RH1000D622 MCR10EZHJ101 100OHM 5% 1/8W R750 0RH1001D622 MCR10EZHJ102 1KOHM 5% 1/8W R751 0RH1502D622 MCR10EZHJ153 15KOHM 5% 1/8W R752 0RH1002D622 MCR10EZHJ103 10KOHM 5% 1/8W R753 0RH1001D622 MCR10EZHJ102 1KOHM 5% 1/8W R754 0RH1000D622 MCR10EZHJ101 100OHM 5% 1/8W R757 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 R758 0RH4703D622 MCR10EZHJ474 470KOHM 5% 1/8 R762 0RH4703D622 MCR10EZHJ474 470KOHM 5% 1/8 R763 0RH4703D622 MCR10EZHJ474 470KOHM 5% 1/8 R901 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 R902 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 R903 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 R904 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 R911 0RH1001D622 MCR10EZHJ102 1KOHM 5% 1/8W R913 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 DATE: 2006. 11. 20. *S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION R914 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 R915 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 R916 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 R917 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 R918 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 R919 0RH2200D622 MCR10EZHJ221 220OHM 5% 1/8W R920 0RH2200D622 MCR10EZHJ221 220OHM 5% 1/8W R921 0RH1000D622 MCR10EZHJ101 100OHM 5% 1/8W R922 0RH1000D622 MCR10EZHJ101 100OHM 5% 1/8W R923 0RH1000D622 MCR10EZHJ101 100OHM 5% 1/8W R924 0RH1000D622 MCR10EZHJ101 100OHM 5% 1/8W R925 0RH1002D622 MCR10EZHJ103 10KOHM 5% 1/8W R349 0RN1002F409 RN-96T1F10K0 10KOHM 1% 1/6W X300 6212AB3004D CSALF2M69G4ZF01-A3 2.696MHZ X301 6212AB2015A HC-49/SM4H 4MHZ 30PPM 4MHZ X500 6202VDT002H SX-1 18.432MHZ 30PPM(16PF) C1002 0CE106WFKDC MVK4.0TP16VC10M 10uF 20% 16 C1003 0CH8226F691 MVK5.0TP16VC22M 22uF 20% 16 C1010 0CH8226F691 MVK5.0TP16VC22M 22uF 20% 16 C1016 0CH8226F691 MVK5.0TP16VC22M 22uF 20% 16 C1020 0CH8226F691 MVK5.0TP16VC22M 22uF 20% 16 C103 0CE476WH6DC MVK8.0TP25VC47M 47uF 20% 25 C1032 0CH8226F691 MVK5.0TP16VC22M 22uF 20% 16 C104 0CE476WH6DC MVK8.0TP25VC47M 47uF 20% 25 C1041 0CH8226F691 MVK5.0TP16VC22M 22uF 20% 16 C1050 0CE106WFKDC MVK4.0TP16VC10M 10uF 20% 16 C1051 0CE106WFKDC MVK4.0TP16VC10M 10uF 20% 16 C1052 0CE106WFKDC MVK4.0TP16VC10M 10uF 20% 16 C1054 0CZZTAT008D RVS-6V470MU-R 47uF 20% 6.3V C106 0CH8106J691 MVK5.0TP35VC10M 10uF 20% 35 C1060 0CE106WFKDC MVK4.0TP16VC10M 10uF 20% 16 C1068 0CE106WFKDC MVK4.0TP16VC10M 10uF 20% 16 C1070 0CE106WFKDC MVK4.0TP16VC10M 10uF 20% 16 C1073 0CE106WFKDC MVK4.0TP16VC10M 10uF 20% 16 C1075 0CE476VF6DC VGV476M016S0ANE010 47uF 20% C1077 0CE106WFKDC MVK4.0TP16VC10M 10uF 20% 16 C1079 0CE106WFKDC MVK4.0TP16VC10M 10uF 20% 16 C1080 0CE476VF6DC VGV476M016S0ANE010 47uF 20% C1085 0CE106WFKDC MVK4.0TP16VC10M 10uF 20% 16 C1108 0CZZTAT008D RVS-6V470MU-R 47uF 20% 6.3V C1114 0CZZTAT008D RVS-6V470MU-R 47uF 20% 6.3V C1116 0CE106WFKDC MVK4.0TP16VC10M 10uF 20% 16 C112 0CE106WFKDC MVK4.0TP16VC10M 10uF 20% 16 C1126 0CE106WFKDC MVK4.0TP16VC10M 10uF 20% 16 C113 0CE477WF6DC MVK10TP16VC470M 470uF 20% 1 C1131 0CE106WFKDC MVK4.0TP16VC10M 10uF 20% 16 C114 0CE477WF6DC MVK10TP16VC470M 470uF 20% 1 C1140 0CH8226F691 MVK5.0TP16VC22M 22uF 20% 16 C121 0CH8476F691 MVK6.3TP16VC47M 47uF 20% 16 C122 0CH8476F691 MVK6.3TP16VC47M 47uF 20% 16 C123 0CH8476F691 MVK6.3TP16VC47M 47uF 20% 16 C134 0CH8476F691 MVK6.3TP16VC47M 47uF 20% 16 C135 0CH8476F691 MVK6.3TP16VC47M 47uF 20% 16 C136 0CH8226F691 MVK5.0TP16VC22M 22uF 20% 16 C138 0CE105WK6DC MVK4.0TP50VC1M 1uF 20% 50V - 26 - MAIN BOARD(DIGITAL) CAPACITOR OTHERs DATE: 2006. 11. 20. *S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION C144 0CE107WF6DC MVK6.3TP16VC100M 100uF 20% C145 0CH8476F691 MVK6.3TP16VC47M 47uF 20% 16 C147 0CE107WF6DC MVK6.3TP16VC100M 100uF 20% C149 0CE105WK6DC MVK4.0TP50VC1M 1uF 20% 50V C200 0CE107WF6DC MVK6.3TP16VC100M 100uF 20% C201 0CH8226F691 MVK5.0TP16VC22M 22uF 20% 16 C202 0CH8476F691 MVK6.3TP16VC47M 47uF 20% 16 C205 0CE477WF6DC MVK10TP16VC470M 470uF 20% 1 C206 0CE107WF6DC MVK6.3TP16VC100M 100uF 20% C207 0CE477WF6DC MVK10TP16VC470M 470uF 20% 1 C212 0CH8476F691 MVK6.3TP16VC47M 47uF 20% 16 C214 0CE106WFKDC MVK4.0TP16VC10M 10uF 20% 16 C217 0CE106WFKDC MVK4.0TP16VC10M 10uF 20% 16 C218 0CH8476F691 MVK6.3TP16VC47M 47uF 20% 16 C219 0CE476WK6DC MVK8.0TP50VC47M 47uF 20% 50 C223 0CE476WK6DC MVK8.0TP50VC47M 47uF 20% 50 C227 0CH8226F691 MVK5.0TP16VC22M 22uF 20% 16 C246 0CE476WK6DC MVK8.0TP50VC47M 47uF 20% 50 C248 0CE476WH6DC MVK8.0TP25VC47M 47uF 20% 25 C255 0CE476WH6DC MVK8.0TP25VC47M 47uF 20% 25 C329 0CE106WFKDC MVK4.0TP16VC10M 10uF 20% 16 C336 0CE106WFKDC MVK4.0TP16VC10M 10uF 20% 16 C401 0CE226WF6DC MVK5.0TP16VC22M 22uF 20% 16 C403 0CE476VF6DC VGV476M016S0ANE010 47uF 20% C409 0CE106WFKDC MVK4.0TP16VC10M 10uF 20% 16 C414 0CE476VF6DC VGV476M016S0ANE010 47uF 20% C415 0CE476WK6DC MVK8.0TP50VC47M 47uF 20% 50 C418 0CE476WK6DC MVK8.0TP50VC47M 47uF 20% 50 C424 0CE226WF6DC MVK5.0TP16VC22M 22uF 20% 16 C438 0CE226WF6DC MVK5.0TP16VC22M 22uF 20% 16 C500 0CH8226F691 MVK5.0TP16VC22M 22uF 20% 16 C503 0CH8226F691 MVK5.0TP16VC22M 22uF 20% 16 C569 0CE106WFKDC MVK4.0TP16VC10M 10uF 20% 16 C587 0CH8226F691 MVK5.0TP16VC22M 22uF 20% 16 C589 0CH8226F691 MVK5.0TP16VC22M 22uF 20% 16 C604 0CE476WH6DC MVK8.0TP25VC47M 47uF 20% 25 C605 0CE476WH6DC MVK8.0TP25VC47M 47uF 20% 25 C618 0CE476WH6DC MVK8.0TP25VC47M 47uF 20% 25 C625 0CE476WH6DC MVK8.0TP25VC47M 47uF 20% 25 C628 0CE476WH6DC MVK8.0TP25VC47M 47uF 20% 25 C731 0CE107VF6DC MV6.3TP16VC100M 100uF 20% 1 C800 0CH8106F691 MVK4.0TP16VC10M 10uF 20% 16 C801 0CE107WH6DC MVK8.0TP25VC100M 100uF 20% C804 0CE107WH6DC MVK8.0TP25VC100M 100uF 20% C806 0CZZTAT006H RV3-16V470ME55U-R4 47uF 20% C902 0CE476WH6DC MVK8.0TP25VC47M 47uF 20% 25 C908 0CE106WFKDC MVK4.0TP16VC10M 10uF 20% 16 C926 0CE106WFKDC MVK4.0TP16VC10M 10uF 20% 16 C929 0CE476WH6DC MVK8.0TP25VC47M 47uF 20% 25 C934 0CH8226F691 MVK5.0TP16VC22M 22uF 20% 16 C939 0CH8226F691 MVK5.0TP16VC22M 22uF 20% 16 C945 0CH8226F691 MVK5.0TP16VC22M 22uF 20% 16 C947 0CH8226F691 MVK5.0TP16VC22M 22uF 20% 16 C961 0CH8226F691 MVK5.0TP16VC22M 22uF 20% 16 C971 0CE476WH6DC MVK8.0TP25VC47M 47uF 20% 25 C983 0CH8226F691 MVK5.0TP16VC22M 22uF 20% 16 C984 0CE106WFKDC MVK4.0TP16VC10M 10uF 20% 16 C1000 0CK104CK56A 0603B104K500CT 100nF 10% 50 C1001 0CK104CK56A 0603B104K500CT 100nF 10% 50 C1005 0CK104CK56A 0603B104K500CT 100nF 10% 50 C1006 0CK104CK56A 0603B104K500CT 100nF 10% 50 C1007 0CK104CK56A 0603B104K500CT 100nF 10% 50 DATE: 2006. 11. 20. *S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION C1008 0CK104CK56A 0603B104K500CT 100nF 10% 50 C1009 0CK104CK56A 0603B104K500CT 100nF 10% 50 C101 0CK103CK56A 0603B103K500CT 10nF 10% 50V C1011 0CK104CK56A 0603B104K500CT 100nF 10% 50 C1012 0CK104CK56A 0603B104K500CT 100nF 10% 50 C1013 0CK104CK56A 0603B104K500CT 100nF 10% 50 C1014 0CK104CK56A 0603B104K500CT 100nF 10% 50 C1015 0CK104CK56A 0603B104K500CT 100nF 10% 50 C1017 0CK104CK56A 0603B104K500CT 100nF 10% 50 C1018 0CK104CK56A 0603B104K500CT 100nF 10% 50 C1019 0CK104CK56A 0603B104K500CT 100nF 10% 50 C1023 0CK104CK56A 0603B104K500CT 100nF 10% 50 C1024 0CK104CK56A 0603B104K500CT 100nF 10% 50 C1025 0CK104CK56A 0603B104K500CT 100nF 10% 50 C1026 0CK104CK56A 0603B104K500CT 100nF 10% 50 C1027 0CK104CK56A 0603B104K500CT 100nF 10% 50 C1028 0CK104CK56A 0603B104K500CT 100nF 10% 50 C1029 0CK104CK56A 0603B104K500CT 100nF 10% 50 C1030 0CK104CK56A 0603B104K500CT 100nF 10% 50 C1031 0CK104CK56A 0603B104K500CT 100nF 10% 50 C1034 0CK104CK56A 0603B104K500CT 100nF 10% 50 C1035 0CK104CK56A 0603B104K500CT 100nF 10% 50 C1036 0CK104CK56A 0603B104K500CT 100nF 10% 50 C1037 0CK104CK56A 0603B104K500CT 100nF 10% 50 C1038 0CK104CK56A 0603B104K500CT 100nF 10% 50 C1042 0CK104CK56A 0603B104K500CT 100nF 10% 50 C1045 0CC101CK41A C1608C0G1H101JT 100pF 5% 50 C1046 0CK473CK56A C1608X7R1H473KT 47nF 10% 50 C1047 0CC331CK41A C1608C0G1H331JT 330pF 5% 50 C1048 0CH5151K416 0805N151J500LT 150pF 5% 50V C105 0CK103CK56A 0603B103K500CT 10nF 10% 50V C1053 0CK104CK56A 0603B104K500CT 100nF 10% 50 C1056 0CK104CK56A 0603B104K500CT 100nF 10% 50 C1061 0CK104CK56A 0603B104K500CT 100nF 10% 50 C1069 0CK104CK56A 0603B104K500CT 100nF 10% 50 C1071 0CK104CK56A 0603B104K500CT 100nF 10% 50 C1072 0CK102CK56A 0603B102K500CT 1nF 10% 50V C1074 0CK104CK56A 0603B104K500CT 100nF 10% 50 C1078 0CK104CK56A 0603B104K500CT 100nF 10% 50 C108 0CK103CK56A 0603B103K500CT 10nF 10% 50V C1081 0CK104CK56A 0603B104K500CT 100nF 10% 50 C1087 0CK104CK56A 0603B104K500CT 100nF 10% 50 C1089 0CK473CH56A C1608X7R1E473KT 47nF 10% 25 C109 0CK104CK56A 0603B104K500CT 100nF 10% 50 C1092 0CK473CH56A C1608X7R1E473KT 47nF 10% 25 C1094 0CK473CH56A C1608X7R1E473KT 47nF 10% 25 C1095 0CK473CH56A C1608X7R1E473KT 47nF 10% 25 C1096 0CK473CH56A C1608X7R1E473KT 47nF 10% 25 C1097 0CK153CK56A 0603B153K500CT 15nF 10% 50V C1098 0CK473CH56A C1608X7R1E473KT 47nF 10% 25 C1099 0CK473CH56A C1608X7R1E473KT 47nF 10% 25 C1100 0CK473CH56A C1608X7R1E473KT 47nF 10% 25 C1101 0CK473CH56A C1608X7R1E473KT 47nF 10% 25 C1110 0CK104CK56A 0603B104K500CT 100nF 10% 50 C1112 0CK104CK56A 0603B104K500CT 100nF 10% 50 C1115 0CK104CK56A 0603B104K500CT 100nF 10% 50 C1117 0CK104CK56A 0603B104K500CT 100nF 10% 50 C1120 0CK104CK56A 0603B104K500CT 100nF 10% 50 C1121 0CK104CK56A 0603B104K500CT 100nF 10% 50 C1122 0CK104CK56A 0603B104K500CT 100nF 10% 50 C1124 0CK104CK56A 0603B104K500CT 100nF 10% 50 C1125 0CK104CK56A 0603B104K500CT 100nF 10% 50 - 27 - DATE: 2006. 11. 20. *S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION C1127 0CK104CK56A 0603B104K500CT 100nF 10% 50 C1128 0CK104CK56A 0603B104K500CT 100nF 10% 50 C1129 0CK104CK56A 0603B104K500CT 100nF 10% 50 C1130 0CK104CK56A 0603B104K500CT 100nF 10% 50 C1132 0CK104CK56A 0603B104K500CT 100nF 10% 50 C1133 0CK104CK56A 0603B104K500CT 100nF 10% 50 C1134 0CK104CK56A 0603B104K500CT 100nF 10% 50 C1135 0CK104CK56A 0603B104K500CT 100nF 10% 50 C1136 0CK104CK56A 0603B104K500CT 100nF 10% 50 C1137 0CK104CK56A 0603B104K500CT 100nF 10% 50 C1138 0CK104CK56A 0603B104K500CT 100nF 10% 50 C1139 0CK104CK56A 0603B104K500CT 100nF 10% 50 C1141 0CK104CK56A 0603B104K500CT 100nF 10% 50 C1142 0CK104CK56A 0603B104K500CT 100nF 10% 50 C1146 0CK104CK56A 0603B104K500CT 100nF 10% 50 C1147 0CK104CK56A 0603B104K500CT 100nF 10% 50 C1148 0CK104CK56A 0603B104K500CT 100nF 10% 50 C1149 0CK104CK56A 0603B104K500CT 100nF 10% 50 C115 0CK104CK56A 0603B104K500CT 100nF 10% 50 C1150 0CK476FD67A LMK325BJ476MM-T 47uF 20% 10 C1151 0CC220CK41A C1608C0G1H220JT 22pF 5% 50V C118 0CK104CK56A 0603B104K500CT 100nF 10% 50 C119 0CK104CK56A 0603B104K500CT 100nF 10% 50 C120 0CK104CK56A 0603B104K500CT 100nF 10% 50 C125 0CH2334F566 0805B334K160CT 330nF 10% 16 C126 0CH2334F566 0805B334K160CT 330nF 10% 16 C127 0CH2334F566 0805B334K160CT 330nF 10% 16 C128 0CK103CK56A 0603B103K500CT 10nF 10% 50V C129 0CK104CK56A 0603B104K500CT 100nF 10% 50 C130 0CK104CK56A 0603B104K500CT 100nF 10% 50 C131 0CK104CK56A 0603B104K500CT 100nF 10% 50 C132 0CK102CK56A 0603B102K500CT 1nF 10% 50V C139 0CK104CK56A 0603B104K500CT 100nF 10% 50 C140 0CK104CK56A 0603B104K500CT 100nF 10% 50 C151 0CK104CK56A 0603B104K500CT 100nF 10% 50 C204 0CK104CK56A 0603B104K500CT 100nF 10% 50 C221 0CK103CK56A 0603B103K500CT 10nF 10% 50V C222 0CK104CK56A 0603B104K500CT 100nF 10% 50 C225 0CK104CK56A 0603B104K500CT 100nF 10% 50 C228 0CK104CK56A 0603B104K500CT 100nF 10% 50 C229 0CK104CK56A 0603B104K500CT 100nF 10% 50 C230 0CK104CK56A 0603B104K500CT 100nF 10% 50 C231 0CK104CK56A 0603B104K500CT 100nF 10% 50 C232 0CK104CK56A 0603B104K500CT 100nF 10% 50 C239 0CK104CK56A 0603B104K500CT 100nF 10% 50 C240 0CK104CK56A 0603B104K500CT 100nF 10% 50 C306 0CK104CK56A 0603B104K500CT 100nF 10% 50 C307 0CK104CK56A 0603B104K500CT 100nF 10% 50 C308 0CK104CK56A 0603B104K500CT 100nF 10% 50 C309 0CK104CK56A 0603B104K500CT 100nF 10% 50 C310 0CK104CK56A 0603B104K500CT 100nF 10% 50 C312 0CK104CK56A 0603B104K500CT 100nF 10% 50 C316 0CK104CK56A 0603B104K500CT 100nF 10% 50 C317 0CK104CK56A 0603B104K500CT 100nF 10% 50 C319 0CK334CF56A C1608X7R1C334KT 330nF 10% 1 C324 0CK104CK56A 0603B104K500CT 100nF 10% 50 C325 0CK104CK56A 0603B104K500CT 100nF 10% 50 C327 0CC221CK41A C1608C0G1H221JT 220pF 5% 50 C328 0CC221CK41A C1608C0G1H221JT 220pF 5% 50 C330 0CK104CK56A 0603B104K500CT 100nF 10% 50 C331 0CK104CK56A 0603B104K500CT 100nF 10% 50 C332 0CK104CK56A 0603B104K500CT 100nF 10% 50 DATE: 2006. 11. 20. *S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION C333 0CK104CK56A 0603B104K500CT 100nF 10% 50 C334 0CK104CK56A 0603B104K500CT 100nF 10% 50 C335 0CK104CK56A 0603B104K500CT 100nF 10% 50 C337 0CK104CK56A 0603B104K500CT 100nF 10% 50 C338 0CK104CK56A 0603B104K500CT 100nF 10% 50 C400 0CK104CK56A 0603B104K500CT 100nF 10% 50 C402 0CK104CK56A 0603B104K500CT 100nF 10% 50 C404 0CK104CK56A 0603B104K500CT 100nF 10% 50 C405 0CK104CK56A 0603B104K500CT 100nF 10% 50 C406 0CK104CK56A 0603B104K500CT 100nF 10% 50 C407 0CK104CK56A 0603B104K500CT 100nF 10% 50 C408 0CK104CK56A 0603B104K500CT 100nF 10% 50 C411 0CK104CK56A 0603B104K500CT 100nF 10% 50 C416 0CK104CK56A 0603B104K500CT 100nF 10% 50 C417 0CK104CK56A 0603B104K500CT 100nF 10% 50 C422 0CK104CK56A 0603B104K500CT 100nF 10% 50 C425 0CK104CK56A 0603B104K500CT 100nF 10% 50 C426 0CK104CK56A 0603B104K500CT 100nF 10% 50 C428 0CK104CK56A 0603B104K500CT 100nF 10% 50 C429 0CK104CK56A 0603B104K500CT 100nF 10% 50 C430 0CK104CK56A 0603B104K500CT 100nF 10% 50 C431 0CK104CK56A 0603B104K500CT 100nF 10% 50 C432 0CK104CK56A 0603B104K500CT 100nF 10% 50 C433 0CK104CK56A 0603B104K500CT 100nF 10% 50 C436 0CK104CK56A 0603B104K500CT 100nF 10% 50 C437 0CK104CK56A 0603B104K500CT 100nF 10% 50 C439 0CK104CK56A 0603B104K500CT 100nF 10% 50 C505 0CK104CK56A 0603B104K500CT 100nF 10% 50 C506 0CK104CK56A 0603B104K500CT 100nF 10% 50 C507 0CK104CK56A 0603B104K500CT 100nF 10% 50 C508 0CK104CK56A 0603B104K500CT 100nF 10% 50 C509 0CK104CK56A 0603B104K500CT 100nF 10% 50 C510 0CK104CK56A 0603B104K500CT 100nF 10% 50 C511 0CK104CK56A 0603B104K500CT 100nF 10% 50 C512 0CK104CK56A 0603B104K500CT 100nF 10% 50 C513 0CK104CK56A 0603B104K500CT 100nF 10% 50 C514 0CK104CK56A 0603B104K500CT 100nF 10% 50 C515 0CK104CK56A 0603B104K500CT 100nF 10% 50 C516 0CK104CK56A 0603B104K500CT 100nF 10% 50 C517 0CK104CK56A 0603B104K500CT 100nF 10% 50 C518 0CK104CK56A 0603B104K500CT 100nF 10% 50 C519 0CK104CK56A 0603B104K500CT 100nF 10% 50 C520 0CK104CK56A 0603B104K500CT 100nF 10% 50 C521 0CK104CK56A 0603B104K500CT 100nF 10% 50 C522 0CK104CK56A 0603B104K500CT 100nF 10% 50 C523 0CK104CK56A 0603B104K500CT 100nF 10% 50 C524 0CK104CK56A 0603B104K500CT 100nF 10% 50 C525 0CK104CK56A 0603B104K500CT 100nF 10% 50 C526 0CK104CK56A 0603B104K500CT 100nF 10% 50 C527 0CK104CK56A 0603B104K500CT 100nF 10% 50 C528 0CK104CK56A 0603B104K500CT 100nF 10% 50 C529 0CK104CK56A 0603B104K500CT 100nF 10% 50 C530 0CK104CK56A 0603B104K500CT 100nF 10% 50 C531 0CK104CK56A 0603B104K500CT 100nF 10% 50 C532 0CK104CK56A 0603B104K500CT 100nF 10% 50 C533 0CK104CK56A 0603B104K500CT 100nF 10% 50 C534 0CK104CK56A 0603B104K500CT 100nF 10% 50 C535 0CK104CK56A 0603B104K500CT 100nF 10% 50 C536 0CK104CK56A 0603B104K500CT 100nF 10% 50 C537 0CK104CK56A 0603B104K500CT 100nF 10% 50 C538 0CK104CK56A 0603B104K500CT 100nF 10% 50 C539 0CK104CK56A 0603B104K500CT 100nF 10% 50 - 28 - DATE: 2006. 11. 20. *S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION C540 0CK104CK56A 0603B104K500CT 100nF 10% 50 C541 0CK104CK56A 0603B104K500CT 100nF 10% 50 C542 0CK104CK56A 0603B104K500CT 100nF 10% 50 C543 0CK104CK56A 0603B104K500CT 100nF 10% 50 C544 0CK104CK56A 0603B104K500CT 100nF 10% 50 C545 0CK104CK56A 0603B104K500CT 100nF 10% 50 C546 0CK104CK56A 0603B104K500CT 100nF 10% 50 C547 0CK104CK56A 0603B104K500CT 100nF 10% 50 C548 0CK104CK56A 0603B104K500CT 100nF 10% 50 C549 0CK104CK56A 0603B104K500CT 100nF 10% 50 C550 0CK104CK56A 0603B104K500CT 100nF 10% 50 C551 0CK104CK56A 0603B104K500CT 100nF 10% 50 C552 0CK104CK56A 0603B104K500CT 100nF 10% 50 C553 0CK104CK56A 0603B104K500CT 100nF 10% 50 C554 0CK104CK56A 0603B104K500CT 100nF 10% 50 C555 0CK104CK56A 0603B104K500CT 100nF 10% 50 C556 0CK104CK56A 0603B104K500CT 100nF 10% 50 C557 0CK104CK56A 0603B104K500CT 100nF 10% 50 C558 0CK104CK56A 0603B104K500CT 100nF 10% 50 C559 0CK104CK56A 0603B104K500CT 100nF 10% 50 C561 0CK104CK56A 0603B104K500CT 100nF 10% 50 C564 0CK103CK56A 0603B103K500CT 10nF 10% 50V C566 0CK104CK56A 0603B104K500CT 100nF 10% 50 C571 0CK103CK56A 0603B103K500CT 10nF 10% 50V C572 0CK104CK56A 0603B104K500CT 100nF 10% 50 C573 0CK104CK56A 0603B104K500CT 100nF 10% 50 C575 0CK104CK56A 0603B104K500CT 100nF 10% 50 C577 0CK104CK56A 0603B104K500CT 100nF 10% 50 C578 0CK104CK56A 0603B104K500CT 100nF 10% 50 C579 0CK104CK56A 0603B104K500CT 100nF 10% 50 C580 0CK104CK56A 0603B104K500CT 100nF 10% 50 C581 0CK104CK56A 0603B104K500CT 100nF 10% 50 C582 0CK104CK56A 0603B104K500CT 100nF 10% 50 C583 0CK104CK56A 0603B104K500CT 100nF 10% 50 C584 0CK104CK56A 0603B104K500CT 100nF 10% 50 C585 0CK104CK56A 0603B104K500CT 100nF 10% 50 C588 0CK104CK56A 0603B104K500CT 100nF 10% 50 C602 0CK104CK56A 0603B104K500CT 100nF 10% 50 C603 0CK104CK56A 0603B104K500CT 100nF 10% 50 C606 0CK104CK56A 0603B104K500CT 100nF 10% 50 C607 0CK104CK56A 0603B104K500CT 100nF 10% 50 C608 0CK104CK56A 0603B104K500CT 100nF 10% 50 C609 0CK104CK56A 0603B104K500CT 100nF 10% 50 C610 0CK104CK56A 0603B104K500CT 100nF 10% 50 C611 0CK104CK56A 0603B104K500CT 100nF 10% 50 C612 0CK104CK56A 0603B104K500CT 100nF 10% 50 C613 0CK104CK56A 0603B104K500CT 100nF 10% 50 C614 0CK104CK56A 0603B104K500CT 100nF 10% 50 C615 0CK104CK56A 0603B104K500CT 100nF 10% 50 C616 0CK104CK56A 0603B104K500CT 100nF 10% 50 C619 0CK104CK56A 0603B104K500CT 100nF 10% 50 C620 0CK104CK56A 0603B104K500CT 100nF 10% 50 C621 0CK104CK56A 0603B104K500CT 100nF 10% 50 C622 0CK104CK56A 0603B104K500CT 100nF 10% 50 C623 0CK104CK56A 0603B104K500CT 100nF 10% 50 C624 0CK104CK56A 0603B104K500CT 100nF 10% 50 C626 0CK104CK56A 0603B104K500CT 100nF 10% 50 C627 0CK103CK56A 0603B103K500CT 10nF 10% 50V C629 0CK104CK56A 0603B104K500CT 100nF 10% 50 C700 0CK104CK56A 0603B104K500CT 100nF 10% 50 C701 0CK104CK56A 0603B104K500CT 100nF 10% 50 C702 0CK104CK56A 0603B104K500CT 100nF 10% 50 DATE: 2006. 11. 20. *S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION C703 0CK104CK56A 0603B104K500CT 100nF 10% 50 C704 0CK104CK56A 0603B104K500CT 100nF 10% 50 C705 0CK104CK56A 0603B104K500CT 100nF 10% 50 C706 0CK104CK56A 0603B104K500CT 100nF 10% 50 C707 0CK104CK56A 0603B104K500CT 100nF 10% 50 C708 0CK104CK56A 0603B104K500CT 100nF 10% 50 C709 0CK104CK56A 0603B104K500CT 100nF 10% 50 C710 0CK104CK56A 0603B104K500CT 100nF 10% 50 C711 0CK104CK56A 0603B104K500CT 100nF 10% 50 C712 0CK104CK56A 0603B104K500CT 100nF 10% 50 C713 0CK104CK56A 0603B104K500CT 100nF 10% 50 C714 0CK104CK56A 0603B104K500CT 100nF 10% 50 C715 0CK104CK56A 0603B104K500CT 100nF 10% 50 C716 0CK104CK56A 0603B104K500CT 100nF 10% 50 C717 0CK104CK56A 0603B104K500CT 100nF 10% 50 C718 0CK104CK56A 0603B104K500CT 100nF 10% 50 C719 0CK104CK56A 0603B104K500CT 100nF 10% 50 C720 0CK104CK56A 0603B104K500CT 100nF 10% 50 C721 0CK104CK56A 0603B104K500CT 100nF 10% 50 C722 0CK104CK56A 0603B104K500CT 100nF 10% 50 C723 0CK104CK56A 0603B104K500CT 100nF 10% 50 C724 0CK104CK56A 0603B104K500CT 100nF 10% 50 C725 0CK104CK56A 0603B104K500CT 100nF 10% 50 C726 0CK104CK56A 0603B104K500CT 100nF 10% 50 C727 0CK104CK56A 0603B104K500CT 100nF 10% 50 C728 0CK104CK56A 0603B104K500CT 100nF 10% 50 C729 0CK104CK56A 0603B104K500CT 100nF 10% 50 C730 0CK472CK56A 0603B472K500CT 4.7nF 10% 50 C736 0CK104CK56A 0603B104K500CT 100nF 10% 50 C807 0CK105CF94A 0603F105Z160CT 1uF -20TO+80 C808 0CK225DK94A CL21F225ZBFNNNE 2.2uF -20TO C809 0CK104CK56A 0603B104K500CT 100nF 10% 50 C810 0CK103CK56A 0603B103K500CT 10nF 10% 50V C811 0CK225DK94A CL21F225ZBFNNNE 2.2uF -20TO C812 0CK104CK56A 0603B104K500CT 100nF 10% 50 C813 0CK103CK56A 0603B103K500CT 10nF 10% 50V C814 0CK105CD56A C1608X7R1A105KT 1uF 10% 10V C815 0CK104CK56A 0603B104K500CT 100nF 10% 50 C816 0CK104CK56A 0603B104K500CT 100nF 10% 50 C817 0CK104CK56A 0603B104K500CT 100nF 10% 50 C818 0CK104CK56A 0603B104K500CT 100nF 10% 50 C819 0CK104CK56A 0603B104K500CT 100nF 10% 50 C820 0CK104CK56A 0603B104K500CT 100nF 10% 50 C821 0CK104CK56A 0603B104K500CT 100nF 10% 50 C822 0CK104CK56A 0603B104K500CT 100nF 10% 50 C823 0CK104CK56A 0603B104K500CT 100nF 10% 50 C824 0CK104CK56A 0603B104K500CT 100nF 10% 50 C825 0CK104CK56A 0603B104K500CT 100nF 10% 50 C826 0CK104CK56A 0603B104K500CT 100nF 10% 50 C827 0CK104CK56A 0603B104K500CT 100nF 10% 50 C828 0CK104CK56A 0603B104K500CT 100nF 10% 50 C829 0CK104CK56A 0603B104K500CT 100nF 10% 50 C830 0CK104CK56A 0603B104K500CT 100nF 10% 50 C831 0CK104CK56A 0603B104K500CT 100nF 10% 50 C832 0CK104CK56A 0603B104K500CT 100nF 10% 50 C833 0CK104CK56A 0603B104K500CT 100nF 10% 50 C834 0CK104CK56A 0603B104K500CT 100nF 10% 50 C835 0CK104CK56A 0603B104K500CT 100nF 10% 50 C836 0CK104CK56A 0603B104K500CT 100nF 10% 50 C837 0CK104CK56A 0603B104K500CT 100nF 10% 50 C838 0CK104CK56A 0603B104K500CT 100nF 10% 50 C839 0CK104CK56A 0603B104K500CT 100nF 10% 50 - 29 - DATE: 2006. 11. 20. *S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION C840 0CK104CK56A 0603B104K500CT 100nF 10% 50 C903 0CK104CK56A 0603B104K500CT 100nF 10% 50 C910 0CK104CK56A 0603B104K500CT 100nF 10% 50 C912 0CK104CK56A 0603B104K500CT 100nF 10% 50 C913 0CK104CK56A 0603B104K500CT 100nF 10% 50 C914 0CK104CK56A 0603B104K500CT 100nF 10% 50 C915 0CK104CK56A 0603B104K500CT 100nF 10% 50 C916 0CK104CK56A 0603B104K500CT 100nF 10% 50 C917 0CK104CK56A 0603B104K500CT 100nF 10% 50 C918 0CK104CK56A 0603B104K500CT 100nF 10% 50 C919 0CK104CK56A 0603B104K500CT 100nF 10% 50 C920 0CK104CK56A 0603B104K500CT 100nF 10% 50 C921 0CK104CK56A 0603B104K500CT 100nF 10% 50 C922 0CK104CK56A 0603B104K500CT 100nF 10% 50 C923 0CK104CK56A 0603B104K500CT 100nF 10% 50 C924 0CK104CK56A 0603B104K500CT 100nF 10% 50 C925 0CK104CK56A 0603B104K500CT 100nF 10% 50 C930 0CK104CK56A 0603B104K500CT 100nF 10% 50 C931 0CK104CK56A 0603B104K500CT 100nF 10% 50 C932 0CK104CK56A 0603B104K500CT 100nF 10% 50 C933 0CK104CK56A 0603B104K500CT 100nF 10% 50 C935 0CK104CK56A 0603B104K500CT 100nF 10% 50 C936 0CK104CK56A 0603B104K500CT 100nF 10% 50 C937 0CK104CK56A 0603B104K500CT 100nF 10% 50 C938 0CK104CK56A 0603B104K500CT 100nF 10% 50 C940 0CK104CK56A 0603B104K500CT 100nF 10% 50 C941 0CK104CK56A 0603B104K500CT 100nF 10% 50 C942 0CK104CK56A 0603B104K500CT 100nF 10% 50 C943 0CK104CK56A 0603B104K500CT 100nF 10% 50 C944 0CK104CK56A 0603B104K500CT 100nF 10% 50 C946 0CK104CK56A 0603B104K500CT 100nF 10% 50 C948 0CK104CK56A 0603B104K500CT 100nF 10% 50 C949 0CK104CK56A 0603B104K500CT 100nF 10% 50 C950 0CK104CK56A 0603B104K500CT 100nF 10% 50 C951 0CK104CK56A 0603B104K500CT 100nF 10% 50 C952 0CK104CK56A 0603B104K500CT 100nF 10% 50 C953 0CK104CK56A 0603B104K500CT 100nF 10% 50 C954 0CK104CK56A 0603B104K500CT 100nF 10% 50 C955 0CK104CK56A 0603B104K500CT 100nF 10% 50 C956 0CK104CK56A 0603B104K500CT 100nF 10% 50 C958 0CK104CK56A 0603B104K500CT 100nF 10% 50 C959 0CK104CK56A 0603B104K500CT 100nF 10% 50 C960 0CK104CK56A 0603B104K500CT 100nF 10% 50 C962 0CK104CK56A 0603B104K500CT 100nF 10% 50 C964 0CK104CK56A 0603B104K500CT 100nF 10% 50 C967 0CC101CK41A C1608C0G1H101JT 100pF 5% 50 C968 0CK473CK56A C1608X7R1H473KT 47nF 10% 50 C969 0CC331CK41A C1608C0G1H331JT 330pF 5% 50 C970 0CH5151K416 0805N151J500LT 150pF 5% 50V C972 0CK104CK56A 0603B104K500CT 100nF 10% 50 C973 0CK104CK56A 0603B104K500CT 100nF 10% 50 C974 0CK104CK56A 0603B104K500CT 100nF 10% 50 C975 0CK104CK56A 0603B104K500CT 100nF 10% 50 C976 0CK104CK56A 0603B104K500CT 100nF 10% 50 C979 0CK104CK56A 0603B104K500CT 100nF 10% 50 C981 0CK104CK56A 0603B104K500CT 100nF 10% 50 C982 0CK104CK56A 0603B104K500CT 100nF 10% 50 C986 0CK104CK56A 0603B104K500CT 100nF 10% 50 C988 0CK104CK56A 0603B104K500CT 100nF 10% 50 C989 0CK104CK56A 0603B104K500CT 100nF 10% 50 C990 0CK104CK56A 0603B104K500CT 100nF 10% 50 C991 0CK104CK56A 0603B104K500CT 100nF 10% 50 DATE: 2006. 11. 20. *S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION C992 0CK104CK56A 0603B104K500CT 100nF 10% 50 C993 0CK104CK56A 0603B104K500CT 100nF 10% 50 C994 0CK104CK56A 0603B104K500CT 100nF 10% 50 C995 0CK104CK56A 0603B104K500CT 100nF 10% 50 C996 0CK104CK56A 0603B104K500CT 100nF 10% 50 C997 0CK104CK56A 0603B104K500CT 100nF 10% 50 C998 0CK104CK56A 0603B104K500CT 100nF 10% 50 C999 0CK104CK56A 0603B104K500CT 100nF 10% 50 C1004 0CK104CK56A 0603B104K500CT 100nF 10% 50 C1033 0CC220CK41A C1608C0G1H220JT 22pF 5% 50V C1039 0CC220CK41A C1608C0G1H220JT 22pF 5% 50V C1043 0CC221CK41A C1608C0G1H221JT 220pF 5% 50 C1044 0CK473CK56A C1608X7R1H473KT 47nF 10% 50 C1057 0CK104CK56A 0603B104K500CT 100nF 10% 50 C1058 0CK104CK56A 0603B104K500CT 100nF 10% 50 C1062 0CK104CK56A 0603B104K500CT 100nF 10% 50 C1063 0CK104CK56A 0603B104K500CT 100nF 10% 50 C1064 0CK104CK56A 0603B104K500CT 100nF 10% 50 C1065 0CK104CK56A 0603B104K500CT 100nF 10% 50 C1066 0CK104CK56A 0603B104K500CT 100nF 10% 50 C1067 0CK104CK56A 0603B104K500CT 100nF 10% 50 C1076 0CK104CK56A 0603B104K500CT 100nF 10% 50 C1082 0CK104CK56A 0603B104K500CT 100nF 10% 50 C1083 0CK104CK56A 0603B104K500CT 100nF 10% 50 C1084 0CK104CK56A 0603B104K500CT 100nF 10% 50 C1086 0CK104CK56A 0603B104K500CT 100nF 10% 50 C1088 0CK473CH56A C1608X7R1E473KT 47nF 10% 25 C1090 0CK153CK56A 0603B153K500CT 15nF 10% 50V C1091 0CK473CH56A C1608X7R1E473KT 47nF 10% 25 C1093 0CK473CH56A C1608X7R1E473KT 47nF 10% 25 C110 0CK104CK56A 0603B104K500CT 100nF 10% 50 C1102 0CH5220K416 0805N220J500LT 22pF 5% 50V C1103 0CK103CK56A 0603B103K500CT 10nF 10% 50V C1104 0CH5220K416 0805N220J500LT 22pF 5% 50V C1105 0CK104CK56A 0603B104K500CT 100nF 10% 50 C1106 0CK104CK56A 0603B104K500CT 100nF 10% 50 C1107 0CK104CK56A 0603B104K500CT 100nF 10% 50 C1109 0CK104CK56A 0603B104K500CT 100nF 10% 50 C111 0CK104CK56A 0603B104K500CT 100nF 10% 50 C1111 0CK103CK56A 0603B103K500CT 10nF 10% 50V C1113 0CK104CK56A 0603B104K500CT 100nF 10% 50 C1118 0CK104CK56A 0603B104K500CT 100nF 10% 50 C1119 0CK104CK56A 0603B104K500CT 100nF 10% 50 C1123 0CK104CK56A 0603B104K500CT 100nF 10% 50 C1144 0CK104CK56A 0603B104K500CT 100nF 10% 50 C116 0CC200CK41A C1608C0G1H200JT 20pF 5% 50V C117 0CC200CK41A C1608C0G1H200JT 20pF 5% 50V C124 0CK104CK56A 0603B104K500CT 100nF 10% 50 C133 0CC561CK41A C1608C0G1H561JT 560pF 5% 50 C137 0CC221CK41A C1608C0G1H221JT 220pF 5% 50 C148 0CK104CK56A 0603B104K500CT 100nF 10% 50 C150 0CK104CK56A 0603B104K500CT 100nF 10% 50 C203 0CK104CK56A 0603B104K500CT 100nF 10% 50 C209 0CK104CK56A 0603B104K500CT 100nF 10% 50 C210 0CK104CK56A 0603B104K500CT 100nF 10% 50 C213 0CK104CK56A 0603B104K500CT 100nF 10% 50 C215 0CK103CK56A 0603B103K500CT 10nF 10% 50V C216 0CK104CK56A 0603B104K500CT 100nF 10% 50 C220 0CK104CK56A 0603B104K500CT 100nF 10% 50 C224 0CK106EF56A C3216X7R1C106KT 10uF 10% 16 C226 0CK106EF56A C3216X7R1C106KT 10uF 10% 16 C236 0CK104CK56A 0603B104K500CT 100nF 10% 50 - 30 - DATE: 2006. 11. 20. *S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION C237 0CK104CK56A 0603B104K500CT 100nF 10% 50 C238 0CK104CK56A 0603B104K500CT 100nF 10% 50 C241 0CC080CK11A C1608C0G1H080DT 8pF 0.5PF 5 C243 0CK104CK56A 0603B104K500CT 100nF 10% 50 C247 0CK104CK56A 0603B104K500CT 100nF 10% 50 C249 0CK103CK56A 0603B103K500CT 10nF 10% 50V C250 0CK104CK56A 0603B104K500CT 100nF 10% 50 C251 0CK104CK56A 0603B104K500CT 100nF 10% 50 C252 0CK104CK56A 0603B104K500CT 100nF 10% 50 C253 0CK104CK56A 0603B104K500CT 100nF 10% 50 C254 0CK103CK56A 0603B103K500CT 10nF 10% 50V C300 0CK104CK56A 0603B104K500CT 100nF 10% 50 C301 0CC220CK41A C1608C0G1H220JT 22pF 5% 50V C302 0CC220CK41A C1608C0G1H220JT 22pF 5% 50V C303 0CC221CK41A C1608C0G1H221JT 220pF 5% 50 C304 0CC821CK41A 0603N821J500LT 820pF 5% 50V C305 0CC331CK41A C1608C0G1H331JT 330pF 5% 50 C311 0CK104CK56A 0603B104K500CT 100nF 10% 50 C313 0CK103CK56A 0603B103K500CT 10nF 10% 50V C314 0CK103CK56A 0603B103K500CT 10nF 10% 50V C315 0CK103CK56A 0603B103K500CT 10nF 10% 50V C318 0CK104CK56A 0603B104K500CT 100nF 10% 50 C320 0CK473CK56A C1608X7R1H473KT 47nF 10% 50 C321 0CK334CF56A C1608X7R1C334KT 330nF 10% 1 C322 0CK334CF56A C1608X7R1C334KT 330nF 10% 1 C323 0CK334CF56A C1608X7R1C334KT 330nF 10% 1 C326 0CK104CK56A 0603B104K500CT 100nF 10% 50 C339 0CK104CK56A 0603B104K500CT 100nF 10% 50 C410 0CK104CK56A 0603B104K500CT 100nF 10% 50 C412 0CK104CK56A 0603B104K500CT 100nF 10% 50 C413 0CK104CK56A 0603B104K500CT 100nF 10% 50 C423 0CK104CK56A 0603B104K500CT 100nF 10% 50 C440 0CK104CK56A 0603B104K500CT 100nF 10% 50 C501 0CK104CK56A 0603B104K500CT 100nF 10% 50 C502 0CK104CK56A 0603B104K500CT 100nF 10% 50 C560 0CK104CK56A 0603B104K500CT 100nF 10% 50 C562 0CK104CK56A 0603B104K500CT 100nF 10% 50 C563 0CK103CK56A 0603B103K500CT 10nF 10% 50V C567 0CK104CK56A 0603B104K500CT 100nF 10% 50 C568 0CK104CK56A 0603B104K500CT 100nF 10% 50 C570 0CK103CK56A 0603B103K500CT 10nF 10% 50V C574 0CK104CK56A 0603B104K500CT 100nF 10% 50 C576 0CK104CK56A 0603B104K500CT 100nF 10% 50 C586 0CK104CK56A 0603B104K500CT 100nF 10% 50 C617 0CK104CK56A 0603B104K500CT 100nF 10% 50 C732 0CK103CK56A 0603B103K500CT 10nF 10% 50V C733 0CK103CK56A 0603B103K500CT 10nF 10% 50V C734 0CK104CK56A 0603B104K500CT 100nF 10% 50 C735 0CK104CK56A 0603B104K500CT 100nF 10% 50 C802 0CK104CK56A 0603B104K500CT 100nF 10% 50 C803 0CK104CK56A 0603B104K500CT 100nF 10% 50 C805 0CK105CF94A 0603F105Z160CT 1uF -20TO+80 C900 0CK104CK56A 0603B104K500CT 100nF 10% 50 C901 0CK104CK56A 0603B104K500CT 100nF 10% 50 C904 0CK103CK56A 0603B103K500CT 10nF 10% 50V C905 0CK476FD67A LMK325BJ476MM-T 47uF 20% 10 C906 0CK104CK56A 0603B104K500CT 100nF 10% 50 C907 0CK104CK56A 0603B104K500CT 100nF 10% 50 C909 0CK104CK56A 0603B104K500CT 100nF 10% 50 C911 0CK104CK56A 0603B104K500CT 100nF 10% 50 C927 0CK104CK56A 0603B104K500CT 100nF 10% 50 C928 0CK103CK56A 0603B103K500CT 10nF 10% 50V DATE: 2006. 11. 20. *S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION C957 0CC220CK41A C1608C0G1H220JT 22pF 5% 50V C963 0CC220CK41A C1608C0G1H220JT 22pF 5% 50V C965 0CC221CK41A C1608C0G1H221JT 220pF 5% 50 C966 0CK473CK56A C1608X7R1H473KT 47nF 10% 50 C977 0CK104CK56A 0603B104K500CT 100nF 10% 50 C978 0CK104CK56A 0603B104K500CT 100nF 10% 50 C980 0CK476FD67A LMK325BJ476MM-T 47uF 20% 10 C985 0CK104CK56A 0603B104K500CT 100nF 10% 50 C987 0CK104CK56A 0603B104K500CT 100nF 10% 50 D300 0DD184009AA KDS184 KDS184 TP KEC - 85V D1012 0DD184009AA KDS184 KDS184 TP KEC - 85V D101 0DS226009AA KDS226 1.2V 85V 300MA 2A 4N D102 0DS226009AA KDS226 1.2V 85V 300MA 2A 4N D100 0DS181009AA KDS181 1.2V 85V 300MA 2A 4N D1000 0DS226009AA KDS226 1.2V 85V 300MA 2A 4N D1001 0DS226009AA KDS226 1.2V 85V 300MA 2A 4N D1004 0DS226009AA KDS226 1.2V 85V 300MA 2A 4N D1005 0DS226009AA KDS226 1.2V 85V 300MA 2A 4N D1006 0DS226009AA KDS226 1.2V 85V 300MA 2A 4N D1007 0DS226009AA KDS226 1.2V 85V 300MA 2A 4N D1010 0DS226009AA KDS226 1.2V 85V 300MA 2A 4N D1011 0DS226009AA KDS226 1.2V 85V 300MA 2A 4N D1002 0DRSE00018B SRV05-4.TCT 1.2V 6V 17.5V 1 D1003 0DRSE00018B SRV05-4.TCT 1.2V 6V 17.5V 1 D1008 0DRSE00018B SRV05-4.TCT 1.2V 6V 17.5V 1 D1009 0DRSE00018B SRV05-4.TCT 1.2V 6V 17.5V 1 ZD400 0DZRM00178A UDZS5.1B 5.1V 4.98TO5.2V 80 ZD401 0DZRM00178A UDZS5.1B 5.1V 4.98TO5.2V 80 ZD402 0DZRM00178A UDZS5.1B 5.1V 4.98TO5.2V 80 ZD403 0DZRM00178A UDZS5.1B 5.1V 4.98TO5.2V 80 ZD404 0DZRM00178A UDZS5.1B 5.1V 4.98TO5.2V 80 IC100 0IPRP00538A FSA1156P6X-NL 1.65TO5.5V 40 IC401 0ICTMLG013A LGDT1901A 3TO3.6V 350NM DIS IC302 0IMCRPH026B PA9516APW 0.5TO7.0 - - 0W 3 IC303 0IMCRPH026B PA9516APW 0.5TO7.0 - - 0W 3 IC402 0IMCRCY001A CY2305SC-1HT 3TO3.6V - - - IC404 0IMCRCY002A CY2309SXC-1HT 3TO3.6V - - - IC1000 0IPH827150A P82B715T 4.5TO12V 15mA - SO IC310 0IPH741400E 74HC14D 2TO6V 0.002mA SCHMI IC706 0ITO741570C TC74LCX157FT 2TO3.6V 0.01mA IC1005 0ICTMLG019A LGDT3303 3TO5 25m 16M TQFP IC1001 0IMMRAL014D AT24C02BN-10SU-1.8 2KBIT 25 IC1006 0IMMRCS012B CAT24WC08W-T(MST3000) 8KBIT IC105 0IMCRAL006A AT24C16AN-10SU-2.7 16KBIT 2 IC300 0IMCRAL021A AT24C512W-10SU-2.7 512KBIT IC1004 0IPRPM3021A MST3385M-LF-80 3TO3.6V_2.25 IC400 0IMI623200B M62320FP(SOP) 4.5TO5.5V 0.0 IC1002 0IPRPFA016A FMS6407MTC20X-NL(PB) 4.75VT IC900 0IPRPFA015B "FMS6400CS1X,LF 4.75VTO5.25V" IC904 0IPRPFA015B "FMS6400CS1X,LF 4.75VTO5.25V" IC1003 0IMCRSJ001B SC1565IST-2.5TR 2.2TO5V 2.5 IC104 0IMCRRH001A BA033FP-E2 4.3TO25V 3.3V 1W IC200 0IPRPML001C "MIC39100-2.5WS,LF 2.3TO26V" IC201 0IMCRRH001A BA033FP-E2 4.3TO25V 3.3V 1W IC202 0IMCRSJ001A SC1565IST-1.8 2.2TO5.5V 1.8 IC205 0IPMGA0010A AZ1117H-3.3 4.75TO10V 3.3V - 31 - DIODEs IC DATE: 2006. 11. 20. *S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION IC501 0IMCRSJ001A SC1565IST-1.8 2.2TO5.5V 1.8 IC601 0IMCRSJ001A SC1565IST-1.8 2.2TO5.5V 1.8 IC800 0IMCRFA020A RC1587DT_36 7V 2.5V 350MW T IC901 0IPMGA0010A AZ1117H-3.3 4.75TO10V 3.3V IC905 0IPMGSG018C LD1086DT15TR 3.4TO30V 1.5V IC101 0ICTMMI057A M37151EFFP 4.5TO5.5V 45mA 8 IC301 0IMCRSS016A S3C44BOX01-EDRO 3TO3.6V 60M IC304 0IMMRMR027E MX29LV320CTTC-70G 32MBIT 4M IC305 0IMMRMR027E MX29LV320CTTC-70G 32MBIT 4M IC403 0IMCRXL004A XC95288XL-10TQG144C 3TO3.6V IC801 0IMMRAT006C EPCS4S18N(PROGRAMED) 0.6TO4 IC802 0IPRPAT002A EP1C12F256C8N 3TO3.6V 2.375 IC705 0ICB841500B "CS8415A-CZR 4.5VTO5.5V,2.85" IC308 0IMMR00141A HY57V641620ETP-6 64MBIT 1MX IC309 0IMMR00141A HY57V641620ETP-6 64MBIT 1MX IC700 0IMMR00141A HY57V641620ETP-6 64MBIT 1MX IC701 0IMMR00141A HY57V641620ETP-6 64MBIT 1MX IC702 0IMMR00141A HY57V641620ETP-6 64MBIT 1MX IC703 0IMMR00141A HY57V641620ETP-6 64MBIT 1MX IC903 0IMMR00080A HY57V161610ETP-6 16MBIT 512 IC704 0IMCRFA014A 74F04SCX 4.5TO5.5V 15.3mA I IC203 0ITH638300C THC63LVDM83R 3VTO3.6V 500MW IC306 0IPRP00009A ICL3232CBNZ 3VTO5.5V - SSOP IC902 0IPRPNE008A "UPD64011BGM-8ED-A 3VTO3.6V," IC906 0IPRPNE008A "UPD64011BGM-8ED-A 3VTO3.6V," IC500 0ICTMLG009C "LGDT1102C HD2.3 3VTO3.6V,1." IC600 0ICTMLG018B "LGDP4411 3VTO3.6V,1.62VTO1." IC106 0IKE704200J KIA7042AF -0.3TO15V 4.2V 50 IC307 0IKE702900G KIA7029AF -0.3TO15V 2.9V 50 IC102 0IMCRSH001A PQ05DZ1U 6TO16V 5V 8W D2PAK IC103 0IMCRSH001A PQ05DZ1U 6TO16V 5V 8W D2PAK L203 6140VB0004B LN-15A1(26UH) 26uH AC500V 5 C341 6210TCE001A HB-1S2012-080JT 8OHM 2X1.25 C342 6210TCE001A HB-1S2012-080JT 8OHM 2X1.25 C344 6210TCE001A HB-1S2012-080JT 8OHM 2X1.25 C347 6210TCE001A HB-1S2012-080JT 8OHM 2X1.25 C348 6210TCE001A HB-1S2012-080JT 8OHM 2X1.25 L1000 0LCML00003B MLB-201209-0120P-N2 120OHM L1001 0LCML00003B MLB-201209-0120P-N2 120OHM L1002 6210TCE001Z HH-1M2012-600JT 60OHM 2X1.2 L1005 6210TCE001Z HH-1M2012-600JT 60OHM 2X1.2 L1011 6210TCE001Z HH-1M2012-600JT 60OHM 2X1.2 L1013 6210TCE001Z HH-1M2012-600JT 60OHM 2X1.2 L107 0LCML00002B MLB-321611-0050P-N1 50OHM 3 L108 0LCML00002B MLB-321611-0050P-N1 50OHM 3 L109 0LCML00002B MLB-321611-0050P-N1 50OHM 3 L202 6210TCE001A HB-1S2012-080JT 8OHM 2X1.25 L204 6210TCE001A HB-1S2012-080JT 8OHM 2X1.25 L224 0LCML00002B MLB-321611-0050P-N1 50OHM 3 L225 0LCML00002B MLB-321611-0050P-N1 50OHM 3 L226 6210TCE001A HB-1S2012-080JT 8OHM 2X1.25 L227 6210TCE001A HB-1S2012-080JT 8OHM 2X1.25 L228 0LCML00002B MLB-321611-0050P-N1 50OHM 3 L229 6210TCE001A HB-1S2012-080JT 8OHM 2X1.25 L230 0LCML00002B MLB-321611-0050P-N1 50OHM 3 L231 0LCML00002A MLB-321611-0120A-N1 120OHM L232 6210TCE001A HB-1S2012-080JT 8OHM 2X1.25 L400 0LCML00003B MLB-201209-0120P-N2 120OHM L401 0LCML00003B MLB-201209-0120P-N2 120OHM DATE: 2006. 11. 20. *S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION L402 0LCML00003B MLB-201209-0120P-N2 120OHM L405 0LCML00003B MLB-201209-0120P-N2 120OHM L406 0LCML00003B MLB-201209-0120P-N2 120OHM L407 0LCML00003B MLB-201209-0120P-N2 120OHM L408 0LCML00003B MLB-201209-0120P-N2 120OHM L502 0LCML00003B MLB-201209-0120P-N2 120OHM L503 0LCML00003B MLB-201209-0120P-N2 120OHM L506 0LCML00003B MLB-201209-0120P-N2 120OHM L600 0LCML00003B MLB-201209-0120P-N2 120OHM L601 0LCML00003B MLB-201209-0120P-N2 120OHM L602 0LCML00003B MLB-201209-0120P-N2 120OHM L603 0LCML00003B MLB-201209-0120P-N2 120OHM L604 0LCML00003B MLB-201209-0120P-N2 120OHM L605 0LCML00003B MLB-201209-0120P-N2 120OHM L606 0LCML00003B MLB-201209-0120P-N2 120OHM L609 0LCML00003B MLB-201209-0120P-N2 120OHM L610 0LCML00003B MLB-201209-0120P-N2 120OHM L700 0LCML00003B MLB-201209-0120P-N2 120OHM L701 0LCML00002A MLB-321611-0120A-N1 120OHM L801 6210TCE001G HH-1M3216-501JT 500OHM 3.2X L803 6210TCE001G HH-1M3216-501JT 500OHM 3.2X L804 6210TCE001G HH-1M3216-501JT 500OHM 3.2X L911 0LCML00003B MLB-201209-0120P-N2 120OHM R559 6210TCE001P HB-1S2012-121JT(H:1mm) 120O AR1058 6210TCE002B HB-4M3216-121JT 120OHM 3.2X AR1061 6210TCE002B HB-4M3216-121JT 120OHM 3.2X AR1088 6210TCE002B HB-4M3216-121JT 120OHM 3.2X AR1089 6210TCE002B HB-4M3216-121JT 120OHM 3.2X AR1090 6210TCE002B HB-4M3216-121JT 120OHM 3.2X AR1091 6210TCE002B HB-4M3216-121JT 120OHM 3.2X C340 6210TCE001A HB-1S2012-080JT 8OHM 2X1.25 C343 6210TCE001A HB-1S2012-080JT 8OHM 2X1.25 C345 6210TCE001A HB-1S2012-080JT 8OHM 2X1.25 C346 6210TCE001A HB-1S2012-080JT 8OHM 2X1.25 C349 6210TCE001A HB-1S2012-080JT 8OHM 2X1.25 L1003 6210TCE001Z HH-1M2012-600JT 60OHM 2X1.2 L1004 6210TCE001Z HH-1M2012-600JT 60OHM 2X1.2 L1010 6210TCE001Z HH-1M2012-600JT 60OHM 2X1.2 L110 0LCML00002B MLB-321611-0050P-N1 50OHM 3 L200 6210TCE001A HB-1S2012-080JT 8OHM 2X1.25 L201 6210TCE001A HB-1S2012-080JT 8OHM 2X1.25 L208 6210TCE001A HB-1S2012-080JT 8OHM 2X1.25 L212 0LCML00002B MLB-321611-0050P-N1 50OHM 3 L216 6210TCE001A HB-1S2012-080JT 8OHM 2X1.25 L220 0LCML00002B MLB-321611-0050P-N1 50OHM 3 L221 6210TCE001A HB-1S2012-080JT 8OHM 2X1.25 L222 6210TCE001A HB-1S2012-080JT 8OHM 2X1.25 L223 6210TCE001A HB-1S2012-080JT 8OHM 2X1.25 L233 6210TCE001A HB-1S2012-080JT 8OHM 2X1.25 L236 6210TCE001A HB-1S2012-080JT 8OHM 2X1.25 L403 0LCML00003B MLB-201209-0120P-N2 120OHM L404 0LCML00003B MLB-201209-0120P-N2 120OHM L500 0LCML00003B MLB-201209-0120P-N2 120OHM L501 0LCML00003B MLB-201209-0120P-N2 120OHM L504 0LCML00003B MLB-201209-0120P-N2 120OHM L505 0LCML00003B MLB-201209-0120P-N2 120OHM L607 0LCML00003B MLB-201209-0120P-N2 120OHM L608 0LCML00003B MLB-201209-0120P-N2 120OHM L800 6210TCE001G HH-1M3216-501JT 500OHM 3.2X L802 6210TCE001G HH-1M3216-501JT 500OHM 3.2X L805 6210TCE001A HB-1S2012-080JT 8OHM 2X1.25 L806 6210TCE001A HB-1S2012-080JT 8OHM 2X1.25 - 32 - COIL & CORE & FILTER & INDUCTOR DATE: 2006. 11. 20. *S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION L807 6210TCE001A HB-1S2012-080JT 8OHM 2X1.25 L808 6210TCE001A HB-1S2012-080JT 8OHM 2X1.25 L809 6210TCE001A HB-1S2012-080JT 8OHM 2X1.25 L901 0LCML00003B MLB-201209-0120P-N2 120OHM L114 6200VJT001A BMK400 LPF(EMI) - 45pF 37NH L115 6200VJT001A BMK400 LPF(EMI) - 45pF 37NH L205 6200VJT001A BMK400 LPF(EMI) - 45pF 37NH L206 6200VJT001A BMK400 LPF(EMI) - 45pF 37NH L207 6200VJT001A BMK400 LPF(EMI) - 45pF 37NH L209 6200VJT001A BMK400 LPF(EMI) - 45pF 37NH L210 6200VJT001A BMK400 LPF(EMI) - 45pF 37NH L211 6200VJT001A BMK400 LPF(EMI) - 45pF 37NH L214 6200VJT001A BMK400 LPF(EMI) - 45pF 37NH L215 6200VJT001A BMK400 LPF(EMI) - 45pF 37NH L217 6200VJT001A BMK400 LPF(EMI) - 45pF 37NH L100 0LCML00020B MLI-201209-6R8K 6.8UH 10% 0 L101 0LCML00020B MLI-201209-6R8K 6.8UH 10% 0 L103 0LC2232101A FI-D3216-223KJT 22UH 10% - L104 0LC2232101A FI-D3216-223KJT 22UH 10% - L105 0LC2232101A FI-D3216-223KJT 22UH 10% - L106 0LC2232101A FI-D3216-223KJT 22UH 10% - L903 0LCML00020B MLI-201209-6R8K 6.8UH 10% 0 L904 0LCML00020B MLI-201209-6R8K 6.8UH 10% 0 L905 0LCML00020B MLI-201209-6R8K 6.8UH 10% 0 L906 0LCML00020B MLI-201209-6R8K 6.8UH 10% 0 L907 0LCML00020B MLI-201209-6R8K 6.8UH 10% 0 L909 0LC1532101A FI-C3216-153KJT 15UH 10% - L910 0LCML00020B MLI-201209-6R8K 6.8UH 10% 0 L914 0LC3332101A FI-D3216-333KJT 33UH 10% - L915 0LC3332101A FI-D3216-333KJT 33UH 10% - L916 0LC3332101A FI-D3216-333KJT 33UH 10% - L917 0LC3332101A FI-D3216-333KJT 33UH 10% - L918 0LC3332101A FI-D3216-333KJT 33UH 10% - L920 0LC1532101A FI-C3216-153KJT 15UH 10% - L1014 0LCML00020B MLI-201209-6R8K 6.8UH 10% 0 L111 0LC4732101A FI-B3216-472KJT 4.7UH 10% - L112 0LC3332101A FI-D3216-333KJT 33UH 10% - L239 0LCML00020B MLI-201209-6R8K 6.8UH 10% 0 L240 0LCML00020B MLI-201209-6R8K 6.8UH 10% 0 L900 0LCML00020B MLI-201209-6R8K 6.8UH 10% 0 L902 0LCML00020B MLI-201209-6R8K 6.8UH 10% 0 L912 0LCML00020B MLI-201209-6R8K 6.8UH 10% 0 L913 0LCML00020B MLI-201209-6R8K 6.8UH 10% 0 L908 0LCML00019B SMI-322522-390K 39UH 10% - L919 0LCML00019B SMI-322522-390K 39UH 10% - Q202 0TF492509AA SI4925DY P-CHANNEL -30V +-2 Q400 0TF492509AA SI4925DY P-CHANNEL -30V +-2 Q100 0TR387500AA 2SC3875S(ALY) NPN 5V 60V 50 Q1007 0TR387500AA 2SC3875S(ALY) NPN 5V 60V 50 Q101 0TR150400BA 2SA1504S(ASY) PNP -5V -50V Q201 0TR387500AA 2SC3875S(ALY) NPN 5V 60V 50 Q300 0TR387500AA 2SC3875S(ALY) NPN 5V 60V 50 Q903 0TR150400BA 2SA1504S(ASY) PNP -5V -50V Q907 0TR150400BA 2SA1504S(ASY) PNP -5V -50V Q1000 0TR387500AA 2SC3875S(ALY) NPN 5V 60V 50 Q1001 0TR387500AA 2SC3875S(ALY) NPN 5V 60V 50 Q1002 0TR387500AA 2SC3875S(ALY) NPN 5V 60V 50 Q1005 0TR387500AA 2SC3875S(ALY) NPN 5V 60V 50 Q1006 0TR387500AA 2SC3875S(ALY) NPN 5V 60V 50 DATE: 2006. 11. 20. *S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION Q102 0TR387500AA 2SC3875S(ALY) NPN 5V 60V 50 Q103 0TR387500AA 2SC3875S(ALY) NPN 5V 60V 50 Q200 0TR387500AA 2SC3875S(ALY) NPN 5V 60V 50 Q301 0TR150400BA 2SA1504S(ASY) PNP -5V -50V Q302 0TR387500AA 2SC3875S(ALY) NPN 5V 60V 50 Q900 0TR150400BA 2SA1504S(ASY) PNP -5V -50V Q901 0TR150400BA 2SA1504S(ASY) PNP -5V -50V Q902 0TR150400BA 2SA1504S(ASY) PNP -5V -50V Q904 0TR150400BA 2SA1504S(ASY) PNP -5V -50V Q905 0TR150400BA 2SA1504S(ASY) PNP -5V -50V Q906 0TR150400BA 2SA1504S(ASY) PNP -5V -50V AR1065 0RJ4701C687 RCA86TRJ4K70 4.7KOHM 5% 1/1 AR1098 0RJ0222C687 RCA86TRJ22R0 22OHM 5% 1/16W AR1099 0RJ0222C687 RCA86TRJ22R0 22OHM 5% 1/16W AR201 0RRZVTA001D RCA86TRJ22R0 22OHM 5% 1/16W AR202 0RRZVTA001D RCA86TRJ22R0 22OHM 5% 1/16W AR203 0RRZVTA001D RCA86TRJ22R0 22OHM 5% 1/16W AR204 0RRZVTA001D RCA86TRJ22R0 22OHM 5% 1/16W AR205 0RRZVTA001D RCA86TRJ22R0 22OHM 5% 1/16W AR227 0RRZVTA001D RCA86TRJ22R0 22OHM 5% 1/16W AR231 0RRZVTA001D RCA86TRJ22R0 22OHM 5% 1/16W AR232 0RRZVTA001D RCA86TRJ22R0 22OHM 5% 1/16W AR233 0RRZVTA001D RCA86TRJ22R0 22OHM 5% 1/16W AR618 0RJ0222C687 RCA86TRJ22R0 22OHM 5% 1/16W AR619 0RJ0222C687 RCA86TRJ22R0 22OHM 5% 1/16W AR620 0RJ0222C687 RCA86TRJ22R0 22OHM 5% 1/16W AR621 0RJ0222C687 RCA86TRJ22R0 22OHM 5% 1/16W AR622 0RJ0222C687 RCA86TRJ22R0 22OHM 5% 1/16W AR623 0RJ0222C687 RCA86TRJ22R0 22OHM 5% 1/16W AR700 0RJ0332C687 RCA86TRJ33R0 33OHM 5% 1/16W AR701 0RJ0332C687 RCA86TRJ33R0 33OHM 5% 1/16W AR702 0RJ0332C687 RCA86TRJ33R0 33OHM 5% 1/16W AR703 0RJ0332C687 RCA86TRJ33R0 33OHM 5% 1/16W AR704 0RJ0332C687 RCA86TRJ33R0 33OHM 5% 1/16W AR705 0RJ0332C687 RCA86TRJ33R0 33OHM 5% 1/16W AR706 0RJ0332C687 RCA86TRJ33R0 33OHM 5% 1/16W AR707 0RJ0332C687 RCA86TRJ33R0 33OHM 5% 1/16W AR708 0RJ0332C687 RCA86TRJ33R0 33OHM 5% 1/16W AR709 0RJ0332C687 RCA86TRJ33R0 33OHM 5% 1/16W AR710 0RJ0332C687 RCA86TRJ33R0 33OHM 5% 1/16W AR711 0RJ0332C687 RCA86TRJ33R0 33OHM 5% 1/16W AR712 0RJ0332C687 RCA86TRJ33R0 33OHM 5% 1/16W AR713 0RJ0332C687 RCA86TRJ33R0 33OHM 5% 1/16W AR714 0RJ0332C687 RCA86TRJ33R0 33OHM 5% 1/16W AR715 0RJ0332C687 RCA86TRJ33R0 33OHM 5% 1/16W AR933 0RJ0222C687 RCA86TRJ22R0 22OHM 5% 1/16W AR934 0RJ0222C687 RCA86TRJ22R0 22OHM 5% 1/16W AR968 0RJ0222C687 RCA86TRJ22R0 22OHM 5% 1/16W AR969 0RJ0222C687 RCA86TRJ22R0 22OHM 5% 1/16W AR983 0RJ0222C687 RCA86TRJ22R0 22OHM 5% 1/16W AR984 0RJ0222C687 RCA86TRJ22R0 22OHM 5% 1/16W L113 0RH1002D622 MCR10EZHJ103 10KOHM 5% 1/8W R101 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R1013 0RJ4701D677 MCR03EZPJ472 4.7KOHM 5% 1/1 R1015 0RJ4701D677 MCR03EZPJ472 4.7KOHM 5% 1/1 R102 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R1029 0RJ3301D677 MCR03EZPJ332 3.3KOHM 5% 1/1 R103 0RJ0822D677 MCR03EZPJ820 82OHM 5% 1/10W R1031 0RJ4701D677 MCR03EZPJ472 4.7KOHM 5% 1/1 - 33 - TRANSISTOR RESISTORs DATE: 2006. 11. 20. *S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION R1038 0RJ3900D677 MCR03EZPJ391 390OHM 5% 1/10 R1044 0RJ0682D677 MCR03EZPJ680 68OHM 5% 1/10W R1048 0RJ0682D677 MCR03EZPJ680 68OHM 5% 1/10W R1050 0RJ0682D677 MCR03EZPJ680 68OHM 5% 1/10W R1052 0RJ0682D677 MCR03EZPJ680 68OHM 5% 1/10W R1057 0RJ0682D677 MCR03EZPJ680 68OHM 5% 1/10W R106 0RJ1002D677 MCR03EZPJ103 10KOHM 5% 1/10 R1060 0RJ0682D677 MCR03EZPJ680 68OHM 5% 1/10W R1062 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R107 0RJ1002D677 MCR03EZPJ103 10KOHM 5% 1/10 R1072 0RJ1002D677 MCR03EZPJ103 10KOHM 5% 1/10 R1074 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R1076 0RJ1002D677 MCR03EZPJ103 10KOHM 5% 1/10 R1077 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R1078 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R1079 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R108 0RJ0102D677 MCR03EZPJ100 10OHM 5% 1/10W R1082 0RJ4701D677 MCR03EZPJ472 4.7KOHM 5% 1/1 R1083 0RJ1001D677 MCR03EZPJ102 1KOHM 5% 1/10W R1084 0RJ1001D677 MCR03EZPJ102 1KOHM 5% 1/10W R1085 0RJ0332D677 MCR03EZPJ330 33OHM 5% 1/10W R1086 0RJ4701D677 MCR03EZPJ472 4.7KOHM 5% 1/1 R109 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R110 0RJ1001D677 MCR03EZPJ102 1KOHM 5% 1/10W R1104 0RJ4701D677 MCR03EZPJ472 4.7KOHM 5% 1/1 R1108 0RJ4701D677 MCR03EZPJ472 4.7KOHM 5% 1/1 R111 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R1112 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R112 0RJ1202D677 MCR03EZPJ123 12KOHM 5% 1/10 R1122 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R1123 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R1124 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R1125 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R1127 0RJ0102D477 MCR03EZPF100 10OHM 1% 1/10W R1128 0RJ0102D477 MCR03EZPF100 10OHM 1% 1/10W R113 0RJ1002D677 MCR03EZPJ103 10KOHM 5% 1/10 R1134 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 R115 0RJ4700D677 MCR03EZPJ471 470OHM 5% 1/10 R124 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R138 0RJ1000D677 MCR03EZPJ101 100OHM 5% 1/10 R140 0RJ1000D677 MCR03EZPJ101 100OHM 5% 1/10 R141 0RJ1000D677 MCR03EZPJ101 100OHM 5% 1/10 R142 0RJ1000D677 MCR03EZPJ101 100OHM 5% 1/10 R153 0RJ4701D677 MCR03EZPJ472 4.7KOHM 5% 1/1 R154 0RJ4701D677 MCR03EZPJ472 4.7KOHM 5% 1/1 R155 0RJ4701D677 MCR03EZPJ472 4.7KOHM 5% 1/1 R156 0RJ4701D677 MCR03EZPJ472 4.7KOHM 5% 1/1 R157 0RJ4701D677 MCR03EZPJ472 4.7KOHM 5% 1/1 R159 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R160 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R170 0RJ4701D677 MCR03EZPJ472 4.7KOHM 5% 1/1 R176 0RJ1004D677 MCR03EZPJ105 1MOHM 5% 1/10W R181 0RJ1000D677 MCR03EZPJ101 100OHM 5% 1/10 R183 0RJ1000D677 MCR03EZPJ101 100OHM 5% 1/10 R186 0RJ1000D677 MCR03EZPJ101 100OHM 5% 1/10 R187 0RJ1000D677 MCR03EZPJ101 100OHM 5% 1/10 R196 0RJ1002D677 MCR03EZPJ103 10KOHM 5% 1/10 R197 0RJ4701D477 MCR03EZPF472 4.7KOHM 1% 1/1 R198 0RJ2202D477 MCR03EZPF223 22KOHM 1% 1/10 R214 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R228 0RJ1002D677 MCR03EZPJ103 10KOHM 5% 1/10 R229 0RJ1001D677 MCR03EZPJ102 1KOHM 5% 1/10W DATE: 2006. 11. 20. *S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION R236 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R314 0RJ4701D477 MCR03EZPF472 4.7KOHM 1% 1/1 R333 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R339 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R341 0RJ4701D477 MCR03EZPF472 4.7KOHM 1% 1/1 R344 0RJ4701D477 MCR03EZPF472 4.7KOHM 1% 1/1 R353 0RJ3901D677 MCR03EZPJ392 3.9KOHM 5% 1/1 R354 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R355 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R356 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R357 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R359 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R360 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R361 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R364 0RJ3901D677 MCR03EZPJ392 3.9KOHM 5% 1/1 R365 0RJ3901D677 MCR03EZPJ392 3.9KOHM 5% 1/1 R366 0RJ3301D477 MCR03EZPF332 3.3KOHM 1% 1/1 R367 0RJ3301D477 MCR03EZPF332 3.3KOHM 1% 1/1 R368 0RJ3301D477 MCR03EZPF332 3.3KOHM 1% 1/1 R369 0RJ3301D477 MCR03EZPF332 3.3KOHM 1% 1/1 R370 0RJ3301D477 MCR03EZPF332 3.3KOHM 1% 1/1 R371 0RJ3301D477 MCR03EZPF332 3.3KOHM 1% 1/1 R389 0RJ4701D477 MCR03EZPF472 4.7KOHM 1% 1/1 R390 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R391 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R392 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R393 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R400 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R401 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R402 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R416 0RJ1000D677 MCR03EZPJ101 100OHM 5% 1/10 R425 0RJ1002D677 MCR03EZPJ103 10KOHM 5% 1/10 R431 0RJ1002D677 MCR03EZPJ103 10KOHM 5% 1/10 R435 0RJ1001D677 MCR03EZPJ102 1KOHM 5% 1/10W R441 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R447 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R448 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R449 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R451 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R456 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R464 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R465 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R487 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R491 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R492 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R493 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R494 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R501 0RJ4701D677 MCR03EZPJ472 4.7KOHM 5% 1/1 R521 0RJ4701D677 MCR03EZPJ472 4.7KOHM 5% 1/1 R525 0RJ1001D677 MCR03EZPJ102 1KOHM 5% 1/10W R526 0RJ1002D677 MCR03EZPJ103 10KOHM 5% 1/10 R528 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R529 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R530 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R537 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R538 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R540 0RJ0272D677 MCR03EZPJ270 27OHM 5% 1/10W R544 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R545 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R546 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R547 0RJ0682D677 MCR03EZPJ680 68OHM 5% 1/10W R548 0RJ0101D677 MCR03EZPJ1R0 1OHM 5% 1/10W - 34 - DATE: 2006. 11. 20. *S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION R549 0RJ1001D677 MCR03EZPJ102 1KOHM 5% 1/10W R550 0RJ1001D677 MCR03EZPJ102 1KOHM 5% 1/10W R552 0RJ4701D677 MCR03EZPJ472 4.7KOHM 5% 1/1 R553 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R555 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R557 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R558 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R560 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R562 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R567 0RJ1820D477 MCR03EZPF1820 182OHM 1% 1/1 R571 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R573 0RJ3301D677 MCR03EZPJ332 3.3KOHM 5% 1/1 R577 0RJ0752D677 MCR03EZPJ750 75OHM 5% 1/10W R579 0RJ0752D677 MCR03EZPJ750 75OHM 5% 1/10W R580 0RJ0752D677 MCR03EZPJ750 75OHM 5% 1/10W R581 0RJ0752D677 MCR03EZPJ750 75OHM 5% 1/10W R600 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R601 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R602 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R603 0RJ4701D677 MCR03EZPJ472 4.7KOHM 5% 1/1 R604 0RJ4701D677 MCR03EZPJ472 4.7KOHM 5% 1/1 R605 0RJ4701D677 MCR03EZPJ472 4.7KOHM 5% 1/1 R606 0RJ4701D677 MCR03EZPJ472 4.7KOHM 5% 1/1 R608 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R617 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R631 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R632 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R650 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R720 0RJ1201D677 MCR03EZPJ122 1.2KOHM 5% 1/1 R802 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R805 0RJ4702D677 MCR03EZPJ473 47KOHM 5% 1/10 R806 0RJ4702D677 MCR03EZPJ473 47KOHM 5% 1/10 R807 0RJ1002D477 MCR03EZPF103 10KOHM 1% 1/10 R824 0RJ1002D477 MCR03EZPF103 10KOHM 1% 1/10 R827 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R831 0RJ1002D477 MCR03EZPF103 10KOHM 1% 1/10 R834 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R835 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R836 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R837 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R838 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R839 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R844 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R901 0RJ4701D677 MCR03EZPJ472 4.7KOHM 5% 1/1 R913 0RJ2202D677 MCR03EZPJ223 22KOHM 5% 1/10 R914 0RJ2202D677 MCR03EZPJ223 22KOHM 5% 1/10 R915 0RJ2202D677 MCR03EZPJ223 22KOHM 5% 1/10 R916 0RJ2202D677 MCR03EZPJ223 22KOHM 5% 1/10 R917 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R918 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R919 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R920 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R921 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R922 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R923 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R927 0RJ2202D677 MCR03EZPJ223 22KOHM 5% 1/10 R930 0RJ2202D677 MCR03EZPJ223 22KOHM 5% 1/10 R931 0RJ2202D677 MCR03EZPJ223 22KOHM 5% 1/10 R932 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R937 0RJ2200D677 MCR03EZPJ221 220OHM 5% 1/10 R939 0RH3600D622 MCR10EZHJ361 360OHM 5% 1/8W R940 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W DATE: 2006. 11. 20. *S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION R945 0RJ4701D677 MCR03EZPJ472 4.7KOHM 5% 1/1 R956 0RJ2202D677 MCR03EZPJ223 22KOHM 5% 1/10 R957 0RJ2202D677 MCR03EZPJ223 22KOHM 5% 1/10 R959 0RJ2202D677 MCR03EZPJ223 22KOHM 5% 1/10 R960 0RJ2202D677 MCR03EZPJ223 22KOHM 5% 1/10 R961 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R962 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R963 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R964 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R965 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R966 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R967 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R977 0RJ2202D677 MCR03EZPJ223 22KOHM 5% 1/10 R978 0RJ2202D677 MCR03EZPJ223 22KOHM 5% 1/10 R979 0RJ2202D677 MCR03EZPJ223 22KOHM 5% 1/10 R982 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R987 0RJ2200D677 MCR03EZPJ221 220OHM 5% 1/10 R989 0RH3600D622 MCR10EZHJ361 360OHM 5% 1/8W R990 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R1000 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R1001 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R1002 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R1003 0RJ1002D677 MCR03EZPJ103 10KOHM 5% 1/10 R1004 0RJ1002D677 MCR03EZPJ103 10KOHM 5% 1/10 R1005 0RJ1002D677 MCR03EZPJ103 10KOHM 5% 1/10 R1006 0RJ1002D677 MCR03EZPJ103 10KOHM 5% 1/10 R1007 0RJ1002D677 MCR03EZPJ103 10KOHM 5% 1/10 R1008 0RJ1002D677 MCR03EZPJ103 10KOHM 5% 1/10 R1010 0RJ3300D677 MCR03EZPJ331 330OHM 5% 1/10 R1011 0RJ3300D677 MCR03EZPJ331 330OHM 5% 1/10 R1012 0RJ3300D677 MCR03EZPJ331 330OHM 5% 1/10 R1016 0RJ0102D677 MCR03EZPJ100 10OHM 5% 1/10W R1017 0RJ0102D677 MCR03EZPJ100 10OHM 5% 1/10W R1018 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R1019 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R1020 0RJ1001D677 MCR03EZPJ102 1KOHM 5% 1/10W R1025 0RJ1000D677 MCR03EZPJ101 100OHM 5% 1/10 R1027 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R1028 0RJ1000D677 MCR03EZPJ101 100OHM 5% 1/10 R1030 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R1034 0RJ1001D677 MCR03EZPJ102 1KOHM 5% 1/10W R1035 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R1036 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R1037 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R1039 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R104 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R1040 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R1041 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R1042 0RJ0332D677 MCR03EZPJ330 33OHM 5% 1/10W R1043 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R1045 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R1046 0RJ4700D677 MCR03EZPJ471 470OHM 5% 1/10 R1047 0RJ0332D677 MCR03EZPJ330 33OHM 5% 1/10W R1049 0RJ0332D677 MCR03EZPJ330 33OHM 5% 1/10W R105 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R1063 0RJ1202D677 MCR03EZPJ123 12KOHM 5% 1/10 R1064 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R1068 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R1069 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R1071 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R1073 0RJ1002D677 MCR03EZPJ103 10KOHM 5% 1/10 R1080 0RJ1001D677 MCR03EZPJ102 1KOHM 5% 1/10W - 35 - DATE: 2006. 11. 20. *S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION R1081 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R1092 0RJ1001D677 MCR03EZPJ102 1KOHM 5% 1/10W R1094 0RJ1001D677 MCR03EZPJ102 1KOHM 5% 1/10W R1095 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R1096 0RJ4701D677 MCR03EZPJ472 4.7KOHM 5% 1/1 R1100 0RJ0512D677 MCR03EZPJ510 51OHM 5% 1/10W R1101 0RJ0512D677 MCR03EZPJ510 51OHM 5% 1/10W R1102 0RJ0512D677 MCR03EZPJ510 51OHM 5% 1/10W R1103 0RJ0512D677 MCR03EZPJ510 51OHM 5% 1/10W R1106 0RJ0332D677 MCR03EZPJ330 33OHM 5% 1/10W R1107 0RJ2201D677 MCR03EZPJ222 2.2KOHM 5% 1/1 R1109 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R1110 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R1111 0RJ3300D677 MCR03EZPJ331 330OHM 5% 1/10 R1114 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R1116 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R1117 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R1118 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R1119 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R1120 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R1121 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R1126 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R116 0RJ0222D477 MCR03EZPF220 22OHM 1% 1/10W R117 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R119 0RJ1002D677 MCR03EZPJ103 10KOHM 5% 1/10 R120 0RJ1002D677 MCR03EZPJ103 10KOHM 5% 1/10 R121 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R122 0RJ1001D677 MCR03EZPJ102 1KOHM 5% 1/10W R123 0RJ3300D477 MCR03EZPF331 330OHM 1% 1/10 R125 0RJ1001D477 MCR03EZPF102 1KOHM 1% 1/10W R130 0RJ1000D677 MCR03EZPJ101 100OHM 5% 1/10 R131 0RJ1000D677 MCR03EZPJ101 100OHM 5% 1/10 R132 0RJ1000D677 MCR03EZPJ101 100OHM 5% 1/10 R133 0RJ1000D677 MCR03EZPJ101 100OHM 5% 1/10 R134 0RJ1000D677 MCR03EZPJ101 100OHM 5% 1/10 R135 0RJ1000D677 MCR03EZPJ101 100OHM 5% 1/10 R136 0RJ1000D677 MCR03EZPJ101 100OHM 5% 1/10 R137 0RJ1000D677 MCR03EZPJ101 100OHM 5% 1/10 R139 0RJ1000D677 MCR03EZPJ101 100OHM 5% 1/10 R143 0RJ1000D677 MCR03EZPJ101 100OHM 5% 1/10 R144 0RJ1000D677 MCR03EZPJ101 100OHM 5% 1/10 R145 0RJ4701D677 MCR03EZPJ472 4.7KOHM 5% 1/1 R149 0RJ4701D677 MCR03EZPJ472 4.7KOHM 5% 1/1 R150 0RJ4701D677 MCR03EZPJ472 4.7KOHM 5% 1/1 R151 0RJ4701D677 MCR03EZPJ472 4.7KOHM 5% 1/1 R152 0RJ4701D677 MCR03EZPJ472 4.7KOHM 5% 1/1 R158 0RJ1004D677 MCR03EZPJ105 1MOHM 5% 1/10W R163 0RJ1002D677 MCR03EZPJ103 10KOHM 5% 1/10 R164 0RJ1000D677 MCR03EZPJ101 100OHM 5% 1/10 R165 0RJ4701D677 MCR03EZPJ472 4.7KOHM 5% 1/1 R167 0RJ4701D677 MCR03EZPJ472 4.7KOHM 5% 1/1 R169 0RJ4701D677 MCR03EZPJ472 4.7KOHM 5% 1/1 R173 0RJ4701D677 MCR03EZPJ472 4.7KOHM 5% 1/1 R174 0RJ4700D677 MCR03EZPJ471 470OHM 5% 1/10 R175 0RJ1001D677 MCR03EZPJ102 1KOHM 5% 1/10W R177 0RJ4702D677 MCR03EZPJ473 47KOHM 5% 1/10 R178 0RJ2001D677 MCR03EZPJ202 2KOHM 5% 1/10W R188 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R189 0RJ1000D677 MCR03EZPJ101 100OHM 5% 1/10 R190 0RJ1000D677 MCR03EZPJ101 100OHM 5% 1/10 R194 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R195 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W DATE: 2006. 11. 20. *S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION R216 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R217 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R222 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R223 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R224 0RJ1002D477 MCR03EZPF103 10KOHM 1% 1/10 R226 0RJ1002D677 MCR03EZPJ103 10KOHM 5% 1/10 R234 0RJ1002D677 MCR03EZPJ103 10KOHM 5% 1/10 R300 0RJ4701D477 MCR03EZPF472 4.7KOHM 1% 1/1 R301 0RJ4701D477 MCR03EZPF472 4.7KOHM 1% 1/1 R302 0RJ4701D477 MCR03EZPF472 4.7KOHM 1% 1/1 R303 0RJ4701D477 MCR03EZPF472 4.7KOHM 1% 1/1 R304 0RJ4701D477 MCR03EZPF472 4.7KOHM 1% 1/1 R305 0RJ4701D477 MCR03EZPF472 4.7KOHM 1% 1/1 R306 0RJ4701D477 MCR03EZPF472 4.7KOHM 1% 1/1 R307 0RJ4701D477 MCR03EZPF472 4.7KOHM 1% 1/1 R308 0RJ4701D477 MCR03EZPF472 4.7KOHM 1% 1/1 R309 0RJ4701D477 MCR03EZPF472 4.7KOHM 1% 1/1 R310 0RJ4701D477 MCR03EZPF472 4.7KOHM 1% 1/1 R311 0RJ4701D477 MCR03EZPF472 4.7KOHM 1% 1/1 R312 0RJ4701D477 MCR03EZPF472 4.7KOHM 1% 1/1 R313 0RJ4701D477 MCR03EZPF472 4.7KOHM 1% 1/1 R315 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R316 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R317 0RJ6201D677 MCR03EZPJ622 6.2KOHM 5% 1/1 R318 0RJ6201D677 MCR03EZPJ622 6.2KOHM 5% 1/1 R319 0RJ4701D477 MCR03EZPF472 4.7KOHM 1% 1/1 R320 0RJ2201D477 MCR03EZPF222 2.2KOHM 1% 1/1 R321 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R322 0RJ2201D477 MCR03EZPF222 2.2KOHM 1% 1/1 R323 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R324 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R325 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R326 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R327 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R328 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R329 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R330 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R334 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R335 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R336 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R337 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R338 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R340 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R342 0RJ4701D477 MCR03EZPF472 4.7KOHM 1% 1/1 R345 0RJ4701D477 MCR03EZPF472 4.7KOHM 1% 1/1 R347 0RJ4701D477 MCR03EZPF472 4.7KOHM 1% 1/1 R348 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R351 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R352 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R362 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R363 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R372 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R373 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R374 0RJ1000D477 MCR03EZPF101 100OHM 1% 1/10 R375 0RJ1000D477 MCR03EZPF101 100OHM 1% 1/10 R376 0RJ1000D477 MCR03EZPF101 100OHM 1% 1/10 R377 0RJ1000D477 MCR03EZPF101 100OHM 1% 1/10 R378 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R379 0RJ1000D477 MCR03EZPF101 100OHM 1% 1/10 R380 0RJ1001D477 MCR03EZPF102 1KOHM 1% 1/10W R381 0RJ1002D477 MCR03EZPF103 10KOHM 1% 1/10 R382 0RJ1000D477 MCR03EZPF101 100OHM 1% 1/10 - 36 - DATE: 2006. 11. 20. *S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION R383 0RJ1000D477 MCR03EZPF101 100OHM 1% 1/10 R384 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R385 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R386 0RJ3300D477 MCR03EZPF331 330OHM 1% 1/10 R387 0RJ1001D677 MCR03EZPJ102 1KOHM 5% 1/10W R388 0RJ1000D477 MCR03EZPF101 100OHM 1% 1/10 R394 0RJ4701D477 MCR03EZPF472 4.7KOHM 1% 1/1 R403 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R404 0RJ1000D677 MCR03EZPJ101 100OHM 5% 1/10 R405 0RJ1000D677 MCR03EZPJ101 100OHM 5% 1/10 R406 0RJ1000D677 MCR03EZPJ101 100OHM 5% 1/10 R407 0RJ4701D677 MCR03EZPJ472 4.7KOHM 5% 1/1 R408 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R409 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R410 0RJ4701D677 MCR03EZPJ472 4.7KOHM 5% 1/1 R411 0RJ4701D677 MCR03EZPJ472 4.7KOHM 5% 1/1 R412 0RJ4701D677 MCR03EZPJ472 4.7KOHM 5% 1/1 R413 0RJ4701D677 MCR03EZPJ472 4.7KOHM 5% 1/1 R415 0RJ6202D677 MCR03EZPJ623 62KOHM 5% 1/10 R417 0RJ1000D677 MCR03EZPJ101 100OHM 5% 1/10 R418 0RJ1002D677 MCR03EZPJ103 10KOHM 5% 1/10 R419 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R420 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R421 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R422 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R423 0RJ4701D677 MCR03EZPJ472 4.7KOHM 5% 1/1 R424 0RJ0272D677 MCR03EZPJ270 27OHM 5% 1/10W R426 0RJ0272D677 MCR03EZPJ270 27OHM 5% 1/10W R428 0RJ0272D677 MCR03EZPJ270 27OHM 5% 1/10W R432 0RJ1602D677 MCR03EZPJ163 16KOHM 5% 1/10 R433 0RJ1001D677 MCR03EZPJ102 1KOHM 5% 1/10W R434 0RJ0682D677 MCR03EZPJ680 68OHM 5% 1/10W R436 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R437 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R439 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R440 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R443 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R444 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R445 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R446 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R453 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R455 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R457 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R458 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R459 0RJ1001D677 MCR03EZPJ102 1KOHM 5% 1/10W R466 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R467 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R468 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R469 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R472 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R473 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R474 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R475 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R476 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R477 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R478 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R480 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R481 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R482 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R483 0RJ1001D677 MCR03EZPJ102 1KOHM 5% 1/10W R484 0RJ1001D677 MCR03EZPJ102 1KOHM 5% 1/10W R485 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W DATE: 2006. 11. 20. *S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION R488 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R490 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R498 0RJ1001D677 MCR03EZPJ102 1KOHM 5% 1/10W R499 0RJ0562D477 MCR03EZPF560 56OHM 1% 1/10W R500 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R502 0RJ4702D677 MCR03EZPJ473 47KOHM 5% 1/10 R503 0RJ4701D677 MCR03EZPJ472 4.7KOHM 5% 1/1 R505 0RJ4701D677 MCR03EZPJ472 4.7KOHM 5% 1/1 R509 0RJ1001D677 MCR03EZPJ102 1KOHM 5% 1/10W R510 0RJ4702D677 MCR03EZPJ473 47KOHM 5% 1/10 R511 0RJ4702D677 MCR03EZPJ473 47KOHM 5% 1/10 R512 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R520 0RJ4701D677 MCR03EZPJ472 4.7KOHM 5% 1/1 R522 0RJ4701D677 MCR03EZPJ472 4.7KOHM 5% 1/1 R523 0RJ4701D677 MCR03EZPJ472 4.7KOHM 5% 1/1 R527 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R531 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R532 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R533 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R534 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R535 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R536 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R541 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R542 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R551 0RJ1001D677 MCR03EZPJ102 1KOHM 5% 1/10W R554 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R556 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R561 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R563 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R564 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R565 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R569 0RJ1820D477 MCR03EZPF1820 182OHM 1% 1/1 R570 0RJ0752D677 MCR03EZPJ750 75OHM 5% 1/10W R572 0RJ0332D677 MCR03EZPJ330 33OHM 5% 1/10W R574 0RJ0332D677 MCR03EZPJ330 33OHM 5% 1/10W R575 0RJ0332D677 MCR03EZPJ330 33OHM 5% 1/10W R576 0RJ0332D677 MCR03EZPJ330 33OHM 5% 1/10W R578 0RJ0752D677 MCR03EZPJ750 75OHM 5% 1/10W R582 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R609 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R610 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R612 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R613 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R614 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R615 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R624 0RJ4701D677 MCR03EZPJ472 4.7KOHM 5% 1/1 R625 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R626 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R627 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R628 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R629 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R630 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R633 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R646 0RJ4701D677 MCR03EZPJ472 4.7KOHM 5% 1/1 R648 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R649 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R651 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R652 0RJ4701D677 MCR03EZPJ472 4.7KOHM 5% 1/1 R716 0RJ0272D677 MCR03EZPJ270 27OHM 5% 1/10W R717 0RJ0272D677 MCR03EZPJ270 27OHM 5% 1/10W R718 0RJ0272D677 MCR03EZPJ270 27OHM 5% 1/10W R719 0RJ0272D677 MCR03EZPJ270 27OHM 5% 1/10W - 37 - DATE: 2006. 11. 20. *S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION R723 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R724 0RJ4702D677 MCR03EZPJ473 47KOHM 5% 1/10 R725 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R726 0RJ0222D477 MCR03EZPF220 22OHM 1% 1/10W R727 0RJ0222D477 MCR03EZPF220 22OHM 1% 1/10W R729 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R730 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R731 0RJ0222D477 MCR03EZPF220 22OHM 1% 1/10W R732 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R733 0RJ0222D477 MCR03EZPF220 22OHM 1% 1/10W R734 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R735 0RJ0222D477 MCR03EZPF220 22OHM 1% 1/10W R736 0RJ4701D477 MCR03EZPF472 4.7KOHM 1% 1/1 R800 0RJ0222D477 MCR03EZPF220 22OHM 1% 1/10W R803 0RJ1000D477 MCR03EZPF101 100OHM 1% 1/10 R804 0RJ0222D477 MCR03EZPF220 22OHM 1% 1/10W R808 0RJ1002D477 MCR03EZPF103 10KOHM 1% 1/10 R809 0RJ1002D477 MCR03EZPF103 10KOHM 1% 1/10 R810 0RJ1002D477 MCR03EZPF103 10KOHM 1% 1/10 R811 0RJ1002D477 MCR03EZPF103 10KOHM 1% 1/10 R812 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R813 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R814 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R815 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R816 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R817 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R818 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R819 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R820 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R821 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R822 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R823 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R825 0RJ1002D477 MCR03EZPF103 10KOHM 1% 1/10 R828 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R829 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R830 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R832 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R833 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R840 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R841 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R842 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R843 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R902 0RJ1500D677 MCR03EZPJ151 150OHM 5% 1/10 R903 0RJ1500D677 MCR03EZPJ151 150OHM 5% 1/10 R904 0RH0912D622 MCR10EZHJ910 91OHM 5% 1/8W R905 0RH0912D622 MCR10EZHJ910 91OHM 5% 1/8W R906 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 R907 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 R908 0RJ2201D677 MCR03EZPJ222 2.2KOHM 5% 1/1 R909 0RJ2201D677 MCR03EZPJ222 2.2KOHM 5% 1/1 R910 0RJ2202D677 MCR03EZPJ223 22KOHM 5% 1/10 R911 0RJ4701D677 MCR03EZPJ472 4.7KOHM 5% 1/1 R912 0RJ2202D677 MCR03EZPJ223 22KOHM 5% 1/10 R924 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R925 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R926 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R935 0RJ0102D677 MCR03EZPJ100 10OHM 5% 1/10W R936 0RJ2200D677 MCR03EZPJ221 220OHM 5% 1/10 R938 0RH3600D622 MCR10EZHJ361 360OHM 5% 1/8W R941 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R946 0RJ1500D677 MCR03EZPJ151 150OHM 5% 1/10 R947 0RJ1500D677 MCR03EZPJ151 150OHM 5% 1/10 DATE: 2006. 11. 20. *S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION R948 0RH0912D622 MCR10EZHJ910 91OHM 5% 1/8W R949 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 R950 0RH0912D622 MCR10EZHJ910 91OHM 5% 1/8W R951 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 R952 0RJ2201D677 MCR03EZPJ222 2.2KOHM 5% 1/1 R953 0RJ2201D677 MCR03EZPJ222 2.2KOHM 5% 1/1 R954 0RJ2202D677 MCR03EZPJ223 22KOHM 5% 1/10 R955 0RJ4701D677 MCR03EZPJ472 4.7KOHM 5% 1/1 R958 0RJ2202D677 MCR03EZPJ223 22KOHM 5% 1/10 R970 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R971 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R972 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R974 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W R975 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R976 0RJ0222D677 MCR03EZPJ220 22OHM 5% 1/10W R985 0RJ0102D677 MCR03EZPJ100 10OHM 5% 1/10W R986 0RJ2200D677 MCR03EZPJ221 220OHM 5% 1/10 R988 0RH3600D622 MCR10EZHJ361 360OHM 5% 1/8W R991 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W X100 6202VDT002D SX-1 8MHZ 30PPM(16PF) 8MHZ X1000 6202TST001A SX-1 14.31818MHZ 30PPM(18PF X300 6212AB2015E HC-49/SM 10MHZ 30PPM 10MHZ X900 6212AB2873A HC-49/SM 24.576MHZ 30PPM 24 X901 6212AB2873A HC-49/SM 24.576MHZ 30PPM 24 LED1000 0DL233309AC SAM2333 RED/Y-GREEN 2.7V 2. LED1001 0DL233309AC SAM2333 RED/Y-GREEN 2.7V 2. X1001 6204B47985K BMS-873R 25MHZ 50PPM 25MHZ X400 6204B62705A VCXO 27MHZ 100PPM 3.3V 0.00 X800 6204B62705A VCXO 27MHZ 100PPM 3.3V 0.00 SW300 EBF32593901 TMUE312GAB 1C1P 12VDC 0.5A TU100 6700AN0002C TDVS-H702P NTSC/ATSC 54HZTO LED100 0DL200000CA SAM5670(DL-2LRG) ROUND 4.8M PRE100 6712000013A TSOP4438SO1 4.5TO5.5V 1.5MA Q102 0TR387500AA 2SC3875S(ALY) NPN 5V 60V 50 Q103 0TR387500AA 2SC3875S(ALY) NPN 5V 60V 50 Q104 0TR387500AA 2SC3875S(ALY) NPN 5V 60V 50 Q105 0TR387500AA 2SC3875S(ALY) NPN 5V 60V 50 Q106 0TR387500AA 2SC3875S(ALY) NPN 5V 60V 50 Q107 0TR387500AA 2SC3875S(ALY) NPN 5V 60V 50 R106 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 R107 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 R108 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 R109 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 R110 0RH4701D622 MCR10EZHJ472 4.7KOHM 5% 1/8 R111 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 R112 0RH4701D622 MCR10EZHJ472 4.7KOHM 5% 1/8 R113 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 R114 0RH4701D622 MCR10EZHJ472 4.7KOHM 5% 1/8 R115 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 R116 0RH4701D622 MCR10EZHJ472 4.7KOHM 5% 1/8 R117 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 R118 0RH4701D622 MCR10EZHJ472 4.7KOHM 5% 1/8 R119 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 R120 0RH4701D622 MCR10EZHJ472 4.7KOHM 5% 1/8 R121 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 R123 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 - 38 - LED BOARD OTHERs DATE: 2006. 11. 20. *S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION R124 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 R125 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 R126 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 R127 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 R128 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 R129 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 R130 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 R131 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 R132 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 R133 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 C100 0CH3104K566 0805B104K500CT 100nF 10% 50 C101 0CH3104K566 0805B104K500CT 100nF 10% 50 C102 0CE106VF6DC VGV106M016S0ANB010 10uF 20% C103 0CE106VF6DC VGV106M016S0ANB010 10uF 20% L100 6210TCE001A HB-1S2012-080JT 8OHM 2X1.25 L101 6210TCE001A HB-1S2012-080JT 8OHM 2X1.25 LED101 0DLBE0158AA BL-HB535A-AV-TRB SUPER BLUE LED102 0DLBE0158AA BL-HB535A-AV-TRB SUPER BLUE LED103 0DLBE0158AA BL-HB535A-AV-TRB SUPER BLUE LED104 0DLBE0158AA BL-HB535A-AV-TRB SUPER BLUE LED105 0DLBE0158AA BL-HB535A-AV-TRB SUPER BLUE LED106 0DLBE0158AA BL-HB535A-AV-TRB SUPER BLUE LED107 0DLBE0158AA BL-HB535A-AV-TRB SUPER BLUE Q100 0TR387500AA 2SC3875S(ALY) NPN 5V 60V 50 Q101 0TR387500AA 2SC3875S(ALY) NPN 5V 60V 50 Q108 0TR387500AA 2SC3875S(ALY) NPN 5V 60V 50 R100 0RH1000D422 MCR10EZHF101 100OHM 1% 1/8W R101 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 R102 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 R103 0RH5600D622 MCR10EZHJ561 560OHM 5% 1/8W R104 0RH5600D622 MCR10EZHJ561 560OHM 5% 1/8W R105 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 R122 0RH4701D622 MCR10EZHJ472 4.7KOHM 5% 1/8 SW200 140-313B KPT-1115AM 1C1P 12VDC 0.05A SW201 140-313B KPT-1115AM 1C1P 12VDC 0.05A SW202 140-313B KPT-1115AM 1C1P 12VDC 0.05A SW203 140-313B KPT-1115AM 1C1P 12VDC 0.05A SW204 140-313B KPT-1115AM 1C1P 12VDC 0.05A SW205 140-313B KPT-1115AM 1C1P 12VDC 0.05A SW206 140-313B KPT-1115AM 1C1P 12VDC 0.05A SW207 140-313B KPT-1115AM 1C1P 12VDC 0.05A KZD200 0DZRM00178A UDZS5.1B 5.1V 4.98TO5.2V 80 KZD201 0DZRM00178A UDZS5.1B 5.1V 4.98TO5.2V 80 R200 0RH7501D622 MCR10EZHJ752 7.5KOHM 5% 1/8 R201 0RH2002D622 MCR10EZHJ203 20KOHM 5% 1/8W R202 0RH1201D622 MCR10EZHJ122 1.2KOHM 5% 1/8 R206 0RH3301D622 MCR10EZHJ332 3.3KOHM 5% 1/8 R216 0RH7501D622 MCR10EZHJ752 7.5KOHM 5% 1/8 R217 0RH2002D622 MCR10EZHJ203 20KOHM 5% 1/8W R218 0RH3301D622 MCR10EZHJ332 3.3KOHM 5% 1/8 R226 0RH1201D622 MCR10EZHJ122 1.2KOHM 5% 1/8 C201 0CH3104K566 0805B104K500CT 100nF 10% 50 R203 0RH4703D622 MCR10EZHJ474 470KOHM 5% 1/8 R204 0RH0752D622 MCR10EZHJ750 75OHM 5% 1/8W R205 0RH0752D622 MCR10EZHJ750 75OHM 5% 1/8W R207 0RH4703D622 MCR10EZHJ474 470KOHM 5% 1/8 DATE: 2006. 11. 20. *S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION R208 0RH4703D622 MCR10EZHJ474 470KOHM 5% 1/8 R209 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 R210 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 R211 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 R212 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 R213 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 R215 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 R227 0RH4703D622 MCR10EZHJ474 470KOHM 5% 1/8 R228 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 R305 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 R306 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 R307 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 R308 0RH0000D622 MCR10EZHJ000 0OHM 5% 1/8W 2 ZD200 0DZRM00178A UDZS5.1B 5.1V 4.98TO5.2V 80 ZD201 0DZRM00178A UDZS5.1B 5.1V 4.98TO5.2V 80 ZD202 0DZRM00178A UDZS5.1B 5.1V 4.98TO5.2V 80 ZD204 0DZRM00178A UDZS5.1B 5.1V 4.98TO5.2V 80 - 39 - SIDE A/V BOARD CONTROL BOARD Nov, 2006 Printed in Korea P/NO : MFL37471801
