TA-VE170 AEP Model UK Model E Model Australian Model Chinese Model SERVICE MANUAL HOME THEATER SYSTEM Manufactured under license from Dolby Laboratories Licensing Corporation. “DOLBY”, “AC-3”, “Pro Logic” and the double-D symbol ; and “Pro Logic” are trademarks of Dolby Laboratories Licensing Corporation. • This set is the Amplifier section in HT-K170. SPECIFICATIONS (DIN 1 kHz, 8 ohms) 25 W + 25 W (DIN 1 kHz, 8 ohms) Front: 25 W / ch Center: 25 W Rear: 25 W / ch TV, VIDEO, DVD 2CH, 5.1 CH/DVD : 10 Hz - 50 kHz +0.5/–2 dB WOOFER: Voltage: 1 V Impedance: 1 kilohms Full mute 220 - 230 V AC, 50/60 Hz 115 W 430 x 274 x 64.5 mm 4.6 kg Power output Rated Power Output at Stereo mode Reference Power Output Frequency response Inputs Outputs Muting Power requirements Power consumption Dimensions Mass (Approx.) TV, VIDEO, DVD 2CH, 5.1 CH/ DVD Sensitivity 250 mV Impedance 50 kilohms S/N (weighting network, input level) 85 *78IHF dB* (A, 250 mV) General Design and specifications are subject to change without notice. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 2 SAFETY-RELATED COMPONENT WARNING!! COMPONENTS IDENTIFIED BY MARK 0 OR DOTTED LINE WITH MARK 0 ON THE SCHEMATIC DIAGRAMS AND IN THE PARTS LIST ARE CRITICAL TO SAFE OPERATION. REPLACE THESE COMPONENTS WITH SONY PARTS WHOSE PART NUMBERS APPEAR AS SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUBLISHED BY SONY. Flexible Circuit Board Repairing • Keep the temperature of soldering iron around 270˚C during repairing. • Do not touch the soldering iron on the same conductor of the circuit board (within 3 times). • Be careful not to apply force on the conductor when soldering or unsoldering. TABLE OF CONTENTS 1. GENERAL ········································································· 3 2. DISASSEMBLY ································································ 4 3. TEST MODE····································································· 5 4. DIAGRAMS ········································································ 6 4-1. Notes for Printed Wiring Board and Schematic Diagram ·················································· 6 4-2. Printed Wiring Board – MAIN Section – ······················ 9 4-3. Schematic Diagram – MAIN Section (1/2) – ·············· 10 4-4. Schematic Diagram – MAIN Section (2/2) – ·············· 11 4-5. Printed Wiring Boards – PANEL Section – ················· 12 4-6. Schematic Diagram – PANEL Section – ····················· 13 4-7. Printed Wiring Boards – POWER Section – ··············· 14 4-8. Schematic Diagram – POWER Section – ···················· 15 4-9. IC Pin Function Description ········································· 16 5. EXPLODED VIEWS ····················································· 17 6. ELECTRICAL PARTS LIST····································· 19 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 3 SECTION 1 GENERAL This section is extracted from instruction manual. 1 5.1 CH/DVD 2 DVD 2CH 3 TV 7 REAR SPEAKERS 8 CENTER SPEAKER 9 Mains lead 4 VIDEO 5 WOOFER FRONT SPEAKER 6 1 5 7 9 8 6 4 2 3 1 3 4 5 6 7 8 2 1 ?/1 button 2 CENTER MODE button 3 VIDEO button 4 TV button 5 DVD 2CH button 6 5-1 CH/DVD button 7 SOUND FIELD button 8 MASTER VOLUME knob www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 4 CASE, FRONT PANEL SECTION MAIN BOARD Note: Follow the disassembly procedure in the numerical order given. 4 case 3 screw (BVTP3 x8) 7 four screws (BVTP3 x8) claw 6 flat wire (CNS301) 2 two tapping screws 1 two tapping screws 5 flat wire (CNS302) claw 8 front panel section 8� Remove the MAIN board to direction of the arrow A 6� connector (CNS800) 5� connector (CNP802) 7� six screws (BVTP3 x8) 1� two screws (BVTP3 x8) 3� six screws (BVTP3 x8) 2� DC fan 4� connector (CNS801) A SECTION 2 DISASSEMBLY www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 5 SECTION 3 TEST MODE This equipment is provided with a test mode built in the microcomputer. The contents are described in the following. [Initial Mode] 1. Press ?/1 button while pressing both [TV] and [5.1CH/DVD] buttons simultaneously. 2. “INITIAL” is displayed on the fluorescent indicator tube, and the status of the unit is set in the following. • All Memory is clear. • Center, rear level set to 0. • Center mode set to NORMAL. • Muting clear. • Volume level set to min. • FAN is on. [Factory Mode] 1. Press ?/1 button while pressing three buttons of [VIDEO], [DVD 2CH], and [5.1CH/DVD] simultaneously. 2. Factory setting same as initial except center mode set to normal using jog can set to volume max or min directly. [FL Check Mode] 1. Press ?/1 button while both [CENTER MODE] and [TV] buttons simultaneously. 2. Fluorescent indicator tube and LED are checked, “FINISH” is displayed and the status of the unit is set back in normal condition. [Gain Up Mode] 1. Press ?/1 button while pressing [SOUND FIELD] button. 2. “NOMAL” is displayed on the fluorescent indicator tube and the rear is gained up 3 dB. 3. To exit from this mode, press two buttons in the same manner as step1. “GAIN LOW” is displayed on the fluorescent indicator tube and the status of the unit is set back in normal condition. [Version Mode] 1. Press ?/1 button while pressing three buttons of [CENTER MODE], [DVD 2CH]and [SOUND FIELD] buttons simultaneously. 2. Version of its destination is displayed on the fluorescent indicator tube. [FAN ON/OFF] • Press ?/1 button while pressing [CENTER MODE] button. • “FAN ON” t fan always turn on. • “FAN AUTO”t when micro computer detected enough input signal fan turn on automatically. Normally fan is off. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 6 • Circuit Boards Location SECTION 4 DIAGRAMS PW.SW borad DISPLAY board JOG board MAIN board STANDBY board PRIMARY board SECONDARY board 4-1. NOTES FOR PRINTED WIRING BOARD AND SCHEMATIC DIAGRAM Note on Schematic Diagram: • All capacitors are in µF unless otherwise noted. pF: µµF 50 WV or less are not indicated except for electrolytics and tantalums. • All resistors are in Ω and 1/4 W or less unless otherwise specified. • ¢ : internal component. • 2 : nonflammable resistor. • C : panel designation. Note on Printed Wiring Board: • X : parts extracted from the component side. • b : Pattern from the side which enables seeing. • Indication of transistor. • U : B+ Line. • V : B– Line. • Voltages and waveforms are dc with respect to ground under no-signal conditions. • Voltages are taken with a VOM (Input impedance 10 MΩ). Voltage variations may be noted due to normal produc- tion tolerances. • Waveforms are taken with a oscilloscope. Voltage variations may be noted due to normal produc- tion tolerances. • Circled numbers refer to waveforms. • Signal path. F : FRONT/AUDIO IN f : REAR E : CENTER j : WOOFER C B These are omitted. E Q B These are omitted. C E Q • Waveforms – MAIN Board – 1 IC300 #¡ (OSC) – DISPLAY Board – 1 IC201 #¢ (X1) 3.4 Vp-p 8 MHz 4.3 Vp-p 4.19 MHz Note: The components identified by mark 0 or dotted line with mark 0 are critical for safety. Replace only with part num- ber specified. Note: www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 7 • IC Block Diagrams – STANDBY Board – IC950 NJM2103D IC500 LC78212 – MAIN Board – IC100 M62447SP 1 2 3 4 5 6 7 8 V+ VSB/SESIN VSA RESET GND OUTC VSC CR VREF + – – + – + – + Q R S 2 1 4 3 6 5 8 7 10 9 12 11 14 13 16 15 18 17 41 42 39 40 37 38 35 36 33 34 31 32 29 30 OUTPUT PORT MICRO COMPUTER INTERFACE DVDD CLK DATA LATCH DGND AGND OUT4 OUT3 OUT2 OUT1 AVDD SW IN GND S SR IN SL IN GND C C IN GND R1 GND R2 GND L1 GND L2 R IN GND LR L IN SW OUT SR OUT SL OUT C OUT R OUT NC L OUT AVSS1 AVSS2 22 – 28 NC 21 – 19 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 CONTROL LATCH SHIFT RESISTOR LEVEL SHIFT CL DI CE VEE OUT IN OUT IN OUT IN VSS S RESET VDD OUT IN IN OUT IN OUT IN www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 8 IC300 LV1035M STRIM OSC VOL VOL VCA VCA A B A B VCA VCA VCA VCA VCA VCA DEV NOISE GEN NOISE FILTER BPF CONTROL CH CONTROL BPF V REF STRIM S MODE RECT RECT DC CUT B NR OUT FILTER DATA DECODER VOL/ MUTE BPF RECT LOGIC FF LOGIC FF RECT C MODE LOGIC LOGIC S S S A A S B B B A B C B L R A A A B A B A B A B A B S VDD PCM PCM CONTROL SRAM IN FILTER R L C S R A B A B A B A B L L R L R R BPF2 R BPF1 S DC OUT C DC OUT R DC OUT L DC OUT V REF VCC C OUT S OUT R OUT L OUT GND L IN R IN S IN DELAY OUT L BPF2 L BPF1 RT IN LT IN DC CUT C MODE GND NS BPF1 OSC NS BPF2 ENABLE DATA CLK DATA CLK VSS OSC OSC VDD A/D NS D/A DC CUT DC CUT VCC DET IREF GND S-OUT R-OUT L-OUT L RECT DC CUT4 R RECT DC CUT3 L BPF3 VLR TH VLR 1 VLR 2 VCS 2 VCS 1 VCS TH L+R RECT DC CUT2 L-R RECT DC CUT1 R BPF3 64 63 62 61 60 59 58 57 56 55 54 53 52 51 50 49 48 47 46 45 44 43 41 40 39 38 37 36 35 34 33 18 17 16 15 14 13 12 11 10 9 7 3 4 5 6 1 2 8 19 20 21 22 23 24 25 26 27 28 29 30 31 32 42 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com TA-VE170 9 9 D100 J-13 D310 C-6 D520 C-12 D521 J-13 D550 I-8 D620 C-11 D621 J-13 D720 C-8 D721 J-7 D731 J-6 D801 G-12 D810 H-12 D811 H-12 D812 H-11 D813 H-11 D814 D-4 D820 I-12 D821 I-12 D822 I-12 D823 I-12 D850 C-13 D853 C-13 IC100 I-2 IC300 E-3 IC302 E-6 IC401 C-4 IC500 G-3 IC501 I-10 IC502 F-6 IC503 F-5 IC601 F-10 IC651 D-10 IC701 E-9 IC751 H-9 IC801 I-6 IC802 I-7 IC803 E-5 Q150 I-5 Q151 I-5 Q152 I-4 Q153 I-4 Q154 I-4 Q155 I-4 Q367 C-6 Q520 D-12 Q550 I-8 Q551 I-9 Q620 D-12 Q720 C-8 Q730 I-7 Q731 I-6 Q732 J-7 Q851 C-13 Q853 B-13 Q854 C-12 Q855 B-13 4-2. PRINTED WIRING BOARD – MAIN Section – • Semiconductor Location Ref. No. Location • See page 6 for Circuit Boards Location. There are a few cases that the part printed on this diagram isn’t mounted in this model. (Page 12) (Page 12) (Page 12) (Page 14) (Page 14) (FAN1) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com TA-VE170 10 10 4-3. SCHEMATIC DIAGRAM – MAIN Section (1/2) – • See page 6 for Waveform. • See page 7 for IC Block Diagrams. R106 100k 2 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com TA-VE170 11 11 4-4. SCHEMATIC DIAGRAM – MAIN Section (2/2) – 1.5k w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com TA-VE170 12 12 4-5. PRINTED WIRING BOARDS – PANEL Section – • Semiconductor Location Ref. No. Location • See page 6 for Circuit Boards Location. There are a few cases that the part printed on this diagram isn’t mounted in this model. (Page 9) (Page 9) . D201 B-11 D202 B-11 D203 C-3 D204 C-3 D211 B-11 D212 B-11 D213 B-11 D214 B-11 D215 B-5 D216 B-5 D217 B-5 D218 B-4 IC201 C-8 IC202 B-10 Q201 C-3 Q202 C-3 Q218 B-2 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com TA-VE170 13 13 4-6. SCHEMATIC DIAGRAM – PANEL Section – • See page 6 for Waveform. • See page 16 for IC Pin Function. (Page 10) (Page 11) PIN FUNCTION w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com TA-VE170 14 14 4-7. PRINTED WIRING BOARDS – POWER Section – • See page 6 for Circuit Boards Location. There are a few cases that the part printed on this diagram isn’t mounted in this model. (Page 9) (Page 9) PC900 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com TA-VE170 15 15 4-8. SCHEMATIC DIAGRAM – POWER Section – • See page 7 for IC Block Diagram. w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 16 16 4-9. IC PIN FUNCTION DESCRIPTION • DISPLAY BOARD IC201 µPD78042FGF-120-3B9 (SYSTEM CONTROLLER, FL/LED DRIVER, KEY CONTROL) Pin No. Pin Name I/O Function 1 to 7 DIG7 to DIG1 O Grid drive signal output to the fluorescent indicator tube (FL201) 8 VDD — Power supply terminal (+5V) 9 S. CLK O Serial data transfer clock signal output to the M62447SP (IC100), LV1035M (IC300) and LC78212 (IC500) 10 S. DATA O Serial data output to the M62447SP (IC100), LV1035M (IC300) and LC78212 (IC500) 11 S. CE (VOL) O Chip enable signal output to the M62447SP (IC100) “H” active 12 S. CE (LC7822) O Chip enable signal output to the LC78212 (IC500) “H” active 13 S. CE (LV1035M) O Chip enable signal output to the LV1035M (IC300) “H” active 14 EN3 O Enable signal output terminal “L” active 15 — Not used 16 PROTECT I I Overload protection input terminal 17 RESET I System reset signal input from the reset signal generator circuit “L”: reset For several hundreds msec. after the power supply rises, “L” is input, then it changes to “H” 18 EN1 O Enable signal output to the function switch (IC402) “L” active 19 EN2 O Enable signal output to the function switch (IC401) “L” active 20 AVSS — Ground terminal (for A/D converter) 21 FAN CLK I Fan motor clock signal input terminal 22 FAN ON I Fan on signal input for the fan motor drive 23 FAN. CNTL O Fan motor control signal output terminal “L”: fan motor on (high speed) “H” : fan low speed 24 MUTING O LED drive signal output of the MUTING LED (D218) “H”: LED on 25 — I Not used (open) 26 A/D III I Key input terminal (A/D input) S205, 206 (5.1 IN, SURROUND MODE keys input) 27 A/D II I Key input terminal (A/D input) S202, 204 (VIDEO, DVD keys input) 28 A/D I I Key input terminal (A/D input) S201, 203 (CENTER MODE, TV keys input) 29 AVDD — Power supply terminal (+5V) (for A/D converter) 30 AVREF I Reference voltage (+5V) input terminal (for A/D converter) 31 XT1 I Sub system clock input terminal Not used (fixed at “L”) 32 XT2 O Sub system clock output terminal Not used (open) 33 VSS — Ground terminal 34 X1 I Main system clock input terminal (4.19 MHz) 35 X2 O Main system clock output terminal (4.19 MHz) 36 SIMULATED O LED drive signal output of the SIMULATED LED (D215) “L”: LED on 37 C. STUDIO O LED drive signal output of the C.STUDIO LED (D216) “L”: LED on 38 PROLOGIC O LED drive signal output of the PROLOGIC LED (D217) “L”: LED on 39 — I Not used (fixed at “L”) 40 PHANTOM O LED drive signal output of the PHANTOM LED (D211) “L”: LED on 41 WIDE O LED drive signal output of the WIDE LED (D212) “L”: LED on 42 NORMAL O LED drive signal output of the NORMAL LED (D213) “L”: LED on 43 3-STEREO O LED drive signal output of the 3 STEREO LED (D214) “L”: LED on 44 SYS. POWER I System power on/off switch (S200 I/u) input terminal 45 ENCODER 2 I Jog dial pulse input from the rotary encoder (RV201 MASTER VOLUME) 46 ENCODER 1 I Jog dial pulse input from the rotary encoder (RV201 MASTER VOLUME) 47 STOP I Power down detection signal input from the NJM2103D (IC950) “L”: power down 48 VSS — Ground terminal 49 SIRCS I Sircs signal input from the remote control receiver (IC202) 50, 51 — I Not used (fixed at “L”) Pin No. Pin Name I/O Function 52 VDD — Power supply terminal (+5V) 53 FAN ON/OFF O Fan on/off control “L” : fan on “H” : fan stop 54 MUTE. S. R O Line muting on/off control signal output for the rear speaker right channel signal “H”: muting on 55 MUTE. S. L O Line muting on/off control signal output for the rear speaker left channel signal “H”: muting on 56 FUNC. MUTE O Line muting on/off control signal output for the front and center speakers signal “H”: muting on 57 VERSION I Setting terminal for the version (fixed at “L” in this set) 58 W. RY O Woofer on/off relay drive signal output terminal “H”: relay on 59 SP. RY O Front speaker on/off relay drive signal output terminal (for protect) “H”: relay on 60 S. RY O Rear speaker on/off relay drive signal output terminal (for protect) “H”: relay on 61 C. RY O Center speaker on/off relay drive signal output terminal (for protect) “H”: relay on 62 POWER. RY O Power on/off relay drive signal output terminal “H”: relay on (power on) 63 to 70 S14 to S7 O Segment drive signal output to the fluorescent indicator tube (FL201) 71 VLOAD — Power supply terminal (–24V) (for FL drive) 72 to 77 S6 to S1 O Segment drive signal output to the fluorescent indicator tube (FL201) 78 — O Not used (open) 79, 80 DIG9, DIG8 O Grid drive signal output to the fluorescent indicator tube (FL201) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 17 SECTION 5 EXPLODED VIEWS • Items marked “*” are not stocked since they are seldom required for routine service. Some delay should be anticipated when ordering these items. • The mechanical parts with no reference num- ber in the exploded views are not supplied. • Accessories and packing materials are given in the last of the electrical parts list. NOTE: • -XX and -X mean standardized parts, so they may have some difference from the original one. • Color Indication of Appearance Parts Example: KNOB, BALANCE (WHITE) . . . (RED) ↑ ↑ Parts Color Cabinet's Color The components identified by mark 0 or dotted line with mark 0 are critical for safety. Replace only with part number specified. (1) CASE, FRONT PANEL SECTION Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 6 5 5 7 8 5 11 9 12 10 9 12 2 1 supplied with RV201 CHASSIS SECTION 4 3 1 4-211-178-01 KNOB (VOL) (BLACK) 1 4-211-178-21 KNOB (VOL) (SILVER) 2 X-4953-052-1 FRONT PANEL ASSY (BLACK) 2 X-4953-053-1 FRONT PANEL ASSY (SILVER) 3 3-008-600-11 EMBLEM (5-AR), SONY 4 1-678-814-11 PW.SW BOARD 5 4-951-620-01 SCREW(2.6X8), +BVTP 6 1-777-353-11 WIRE(FLAT TYPE) (15 CORE) 7 A-4473-758-A DISPLAY BOARD,COMPLETE 8 1-769-973-11 WIRE(FLAT TYPE) (13 CORE) 9 3-710-901-11 SCREW, TAPPING (BLACK) 9 4-210-291-11 SCREW (CASE 3 TP2)(SILVER) 10 4-211-182-51 CASE (SILVER) * 10 4-211-182-01 CASE (BLACK) 11 1-678-808-11 JOG BOARD 12 7-685-646-79 SCREW +BVTP3X8 TYPE2 N-S www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 18 (2) CHASSIS SECTION Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 60 59 61 58 58 58 62 51 52 56 55 54 54 53 53 T900 FAN1 PC900 63 57 58 58 * 51 4-211-183-21 CHASSIS PANEL 52 1-678-812-11 SECONDARY BOARD 53 4-212-070-01 INSULATOR (PT) 54 3-531-576-11 RIVET 55 7-685-880-09 SCREW +BVTT4X6 (S) 56 1-678-811-11 PRIMARY BOARD 57 A-4473-760-A STANDBY BOARD,COMPLETE 58 7-685-646-79 SCREW +BVTP3X8 TYPE2 N-S 59 A-4473-763-A MAIN BOARD,COMPLETE * 60 4-924-098-21 HOLDER, PC BOARD * 61 3-703-244-00 BUSHING (2104), CORD 62 4-965-822-01 FOOT 63 4-214-557-11 CUSHION FAN1 1-763-137-11 FAN, DC 0T900 1-431-979-11 TRANSFORMER, POWER 0PC900 1-777-071-21 CORD, POWER The components identified by mark 0 or dotted line with mark 0 are critical for safety. Replace only with part number specified. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 19 SECTION 6 ELECTRICAL PARTS LIST NOTE: • Due to standardization, replacements in the parts list may be different from the parts specified in the diagrams or the components used on the set. • -XX and -X mean standardized parts, so they may have some difference from the original one. • RESISTORS All resistors are in ohms. METAL: Metal-film resistor. METAL OXIDE: Metal oxide-film resistor. F: nonflammable • Items marked “*” are not stocked since they are seldom required for routine service. Some delay should be anticipated when order- ing these items. • SEMICONDUCTORS In each case, u: µ, for example: uA. . : µA. . uPA. . : µPA. . uPB. . : µPB. . uPC. . : µPC. . uPD. . : µPD. . • CAPACITORS uF: µF • COILS uH: µH The components identified by mark 0 or dotted line with mark 0 are critical for safety. Replace only with part number specified. When indicating parts by reference number, please include the board name. Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark A-4473-758-A DISPLAY BOARD, COMPLETE *********************** * 4-921-941-01 CUSHION (FL) * 4-943-107-11 HOLDER (FL TUBE) < CAPACITOR > C201 1-104-905-11 CAPACITOR 0.22F 5.5V C202 1-164-159-11 CERAMIC 0.1uF 50V C203 1-162-294-31 CERAMIC 0.001uF 10% 50V C204 1-124-261-00 ELECT 10uF 20% 50V C205 1-124-465-00 ELECT 0.47uF 20% 50V C206 1-164-159-11 CERAMIC 0.1uF 50V C207 1-162-282-31 CERAMIC 100PF 10% 50V C208 1-162-282-31 CERAMIC 100PF 10% 50V C210 1-164-159-11 CERAMIC 0.1uF 50V C211 1-164-159-11 CERAMIC 0.1uF 50V C212 1-164-159-11 CERAMIC 0.1uF 50V < CONNECTOR > * CNP203 1-565-295-11 PLUG, CONNECTOR 4P * CNS201 1-569-306-11 SOCKET, CONNECTOR (L TYPE) 15P CNS202 1-568-444-11 SOCKET, CONNECTOR 13P * CNS203 1-565-480-11 CONNECTOR, BOARD TO BOARD 4P CNS802 1-770-480-11 SOCKET, CONNECTOR PIN 4P < DIODE > D201 8-719-911-19 DIODE 1SS133T-72 D202 8-719-911-19 DIODE 1SS133T-72 D203 8-719-911-19 DIODE 1SS133T-72 D204 8-719-911-19 DIODE 1SS133T-72 D211 8-719-046-36 DIODE SEL5921A-TP15 (PHANTOM) D212 8-719-046-36 DIODE SEL5921A-TP15 (WIDE) D213 8-719-046-36 DIODE SEL5921A-TP15 (NORMAL) D214 8-719-046-36 DIODE SEL5921A-TP15 (3 STEREO) D215 8-719-046-36 DIODE SEL5921A-TP15 (SIMULATED) D216 8-719-046-36 DIODE SEL5921A-TP15 (C. STUDIO) D217 8-719-046-36 DIODE SEL5921A-TP15 (PRO LOGIC) D218 8-719-046-36 DIODE SEL5921A-TP15 (MUTING) < FILTER > FL201 1-517-786-11 INDICATOR TUBE, FLUORESCENT < IC > IC201 8-759-683-98 IC uPD78042FGF-120-3B9 IC202 8-759-332-18 IC GP1U27XB < COIL > L201 1-410-509-11 INDUCTOR 10uH < TRANSISTOR > Q201 8-729-900-63 TRANSISTOR BN1F4M-TP Q202 8-729-900-36 TRANSISTOR BA1F4M-TP Q218 8-729-119-76 TRANSISTOR 2SA1115TP-F < RESISTOR > R200 1-249-433-11 CARBON 22K 5% 1/4W R201 1-247-903-00 CARBON 1M 5% 1/4W R203 1-249-441-11 CARBON 100K 5% 1/4W R204 1-249-425-11 CARBON 4.7K 5% 1/4W F R205 1-249-437-11 CARBON 47K 5% 1/4W R206 1-249-429-11 CARBON 10K 5% 1/4W R207 1-249-429-11 CARBON 10K 5% 1/4W R208 1-249-429-11 CARBON 10K 5% 1/4W R209 1-249-433-11 CARBON 22K 5% 1/4W R210 1-247-807-31 CARBON 100 5% 1/4W R211 1-247-807-31 CARBON 100 5% 1/4W R215 1-247-807-31 CARBON 100 5% 1/4W R219 1-249-409-11 CARBON 220 5% 1/4W F R221 1-247-807-31 CARBON 100 5% 1/4W R222 1-247-807-31 CARBON 100 5% 1/4W R223 1-247-807-31 CARBON 100 5% 1/4W R224 1-247-807-31 CARBON 100 5% 1/4W R225 1-247-807-31 CARBON 100 5% 1/4W R226 1-247-807-31 CARBON 100 5% 1/4W R227 1-249-433-11 CARBON 22K 5% 1/4W R228 1-249-433-11 CARBON 22K 5% 1/4W R229 1-249-425-11 CARBON 4.7K 5% 1/4W F R230 1-249-429-11 CARBON 10K 5% 1/4W R231 1-249-425-11 CARBON 4.7K 5% 1/4W F R232 1-249-425-11 CARBON 4.7K 5% 1/4W F R233 1-249-425-11 CARBON 4.7K 5% 1/4W F R234 1-249-425-11 CARBON 4.7K 5% 1/4W F R235 1-249-425-11 CARBON 4.7K 5% 1/4W F R236 1-249-425-11 CARBON 4.7K 5% 1/4W F R238 1-249-441-11 CARBON 100K 5% 1/4W < SWITCH > S201 1-762-875-21 SWITCH, KEYBOARD (CENTER MODE) S202 1-762-875-21 SWITCH, KEYBOARD (DVD 2CH) S203 1-762-875-21 SWITCH, KEYBOARD (VIDEO) S204 1-762-875-21 SWITCH, KEYBOARD (TV) S205 1-762-875-21 SWITCH, KEYBOARD (5.1CH/DVD) DISPLAY www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks 20 S206 1-762-875-21 SWITCH, KEYBOARD (SOUND FIELD) < VIBRATOR > X201 1-577-101-11 VIBRATOR, CERAMIC (4.19MHz) ************************************************************ 1-678-808-11 JOG BOARD ********* < VARIABLE RESISTOR > RV201 1-475-886-11 ENCODER, ROTARY (MASTER VOLUME) ************************************************************ A-4473-763-A MAIN BOARD, COMPLETE ********************* 3-531-576-11 RIVET 7-685-647-79 SCREW +BVTP 3X10 TYPE2 N-S 7-685-872-09 SCREW +BVTT 3X8 (S) < CAPACITOR > C101 1-126-163-11 ELECT 4.7uF 20% 50V C102 1-126-163-11 ELECT 4.7uF 20% 50V C103 1-126-163-11 ELECT 4.7uF 20% 50V C104 1-126-163-11 ELECT 4.7uF 20% 50V C105 1-126-163-11 ELECT 4.7uF 20% 50V C106 1-126-163-11 ELECT 4.7uF 20% 50V C107 1-162-291-31 CERAMIC 560PF 10.00% 50V C108 1-126-163-11 ELECT 4.7uF 20% 50V C109 1-126-163-11 ELECT 4.7uF 20% 50V C110 1-126-163-11 ELECT 4.7uF 20% 50V C111 1-126-163-11 ELECT 4.7uF 20% 50V C112 1-126-163-11 ELECT 4.7uF 20% 50V C113 1-126-163-11 ELECT 4.7uF 20% 50V C114 1-164-159-11 CERAMIC 0.1uF 50V C115 1-126-964-11 ELECT 10uF 20.00% 50V C116 1-126-964-11 ELECT 10uF 20.00% 50V C117 1-164-159-11 CERAMIC 0.1uF 50V C118 1-164-159-11 CERAMIC 0.1uF 50V C119 1-126-964-11 ELECT 10uF 20.00% 50V C150 1-164-159-11 CERAMIC 0.1uF 50V C151 1-164-159-11 CERAMIC 0.1uF 50V C152 1-164-159-11 CERAMIC 0.1uF 50V C153 1-164-159-11 CERAMIC 0.1uF 50V C154 1-164-159-11 CERAMIC 0.1uF 50V C155 1-164-159-11 CERAMIC 0.1uF 50V C302 1-126-934-11 ELECT 220uF 20.00% 10V C303 1-130-494-11 MYLAR 0.082uF 5% 50V C304 1-137-367-11 MYLAR 0.0033uF 5.00% 50V C305 1-130-494-11 MYLAR 0.082uF 5% 50V C306 1-126-959-11 ELECT 0.47uF 20.00% 50V C307 1-126-964-11 ELECT 10uF 20.00% 50V C308 1-126-964-11 ELECT 10uF 20.00% 50V C309 1-162-291-31 CERAMIC 560PF 10.00% 50V C310 1-126-962-11 ELECT 3.3uF 20.00% 50V C311 1-126-961-11 ELECT 2.2uF 20.00% 50V C312 1-126-934-11 ELECT 220uF 20.00% 10V C313 1-126-934-11 ELECT 220uF 20.00% 10V C314 1-136-165-00 MYLAR 0.1uF 5.00% 50V C315 1-164-159-11 CERAMIC 0.1uF 50V C316 1-124-252-00 ELECT 0.33uF 20% 50V C317 1-164-159-11 CERAMIC 0.1uF 50V C318 1-136-357-11 MYLAR 680PF 5.00% 50V C322 1-126-962-11 ELECT 3.3uF 20.00% 50V C323 1-136-173-00 MYLAR 0.47uF 5.00% 50V C324 1-104-664-11 ELECT 47uF 20.00% 16V C325 1-136-165-00 MYLAR 0.1uF 5.00% 50V C326 1-136-165-00 MYLAR 0.1uF 5.00% 50V C327 1-126-959-11 ELECT 0.47uF 20.00% 50V C328 1-126-163-11 ELECT 4.7uF 20% 50V C329 1-126-959-11 ELECT 0.47uF 20.00% 50V C330 1-126-163-11 ELECT 4.7uF 20% 50V C331 1-124-250-11 ELECT 0.15uF 20.00% 50V C332 1-126-962-11 ELECT 3.3uF 20.00% 50V C333 1-124-250-11 ELECT 0.15uF 20.00% 50V C334 1-137-372-11 MYLAR 0.022uF 5.00% 50V C335 1-136-161-00 MYLAR 0.047uF 5.00% 50V C336 1-126-934-11 ELECT 220uF 20.00% 10V C337 1-126-964-11 ELECT 10uF 20.00% 50V C338 1-126-964-11 ELECT 10uF 20.00% 50V C339 1-126-964-11 ELECT 10uF 20.00% 50V C340 1-126-964-11 ELECT 10uF 20.00% 50V C341 1-126-934-11 ELECT 220uF 20.00% 10V C342 1-126-962-11 ELECT 3.3uF 20.00% 50V C343 1-126-962-11 ELECT 3.3uF 20.00% 50V C344 1-136-165-00 MYLAR 0.1uF 5.00% 50V C345 1-136-165-00 MYLAR 0.1uF 5.00% 50V C346 1-126-959-11 ELECT 0.47uF 20.00% 50V C347 1-126-163-11 ELECT 4.7uF 20% 50V C348 1-126-959-11 ELECT 0.47uF 20.00% 50V C349 1-126-163-11 ELECT 4.7uF 20% 50V C350 1-124-250-11 ELECT 0.15uF 20.00% 50V C351 1-126-962-11 ELECT 3.3uF 20.00% 50V C352 1-124-250-11 ELECT 0.15uF 20.00% 50V C357 1-164-159-11 CERAMIC 0.1uF 50V C359 1-126-163-11 ELECT 4.7uF 20% 50V C360 1-126-163-11 ELECT 4.7uF 20% 50V C361 1-164-159-11 CERAMIC 0.1uF 50V C362 1-162-294-31 CERAMIC 0.001uF 10% 50V C370 1-164-159-11 CERAMIC 0.1uF 50V C371 1-126-966-11 ELECT 33uF 20.00% 16V C401 1-164-159-11 CERAMIC 0.1uF 50V C402 1-164-159-11 CERAMIC 0.1uF 50V C501 1-126-163-11 ELECT 4.7uF 20% 50V C502 1-162-282-31 CERAMIC 100PF 10% 50V C503 1-162-282-31 CERAMIC 100PF 10% 50V C504 1-102-942-00 CERAMIC 5.0PF 50V C506 1-104-665-11 ELECT 100uF 20.00% 16V C507 1-126-160-11 ELECT 1uF 20% 50V C509 1-137-372-11 MYLAR 0.022uF 5.00% 50V C511 1-126-163-11 ELECT 4.7uF 20% 50V DISPLAY JOG MAIN www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks 21 C512 1-126-163-11 ELECT 4.7uF 20% 50V C513 1-126-163-11 ELECT 4.7uF 20% 50V C514 1-126-160-11 ELECT 1uF 20% 50V C515 1-164-159-11 CERAMIC 0.1uF 50V C516 1-126-163-11 ELECT 4.7uF 20% 50V C517 1-162-193-31 CERAMIC 3.3PF 10.00% 50V C519 1-126-160-11 ELECT 1uF 20% 50V C551 1-126-163-11 ELECT 4.7uF 20% 50V C553 1-126-160-11 ELECT 1uF 20% 50V C554 1-126-163-11 ELECT 4.7uF 20% 50V C555 1-126-514-11 ELECT 22uF 20.00% 10V C567 1-162-193-31 CERAMIC 3.3PF 10.00% 50V C601 1-126-163-11 ELECT 4.7uF 20% 50V C602 1-162-282-31 CERAMIC 100PF 10% 50V C603 1-162-282-31 CERAMIC 100PF 10% 50V C604 1-102-942-00 CERAMIC 5.0PF 50V C605 1-104-665-11 ELECT 100uF 20.00% 16V C607 1-126-160-11 ELECT 1uF 20% 50V C609 1-137-372-11 MYLAR 0.022uF 5.00% 50V C610 1-126-160-11 ELECT 1uF 20% 50V C651 1-126-163-11 ELECT 4.7uF 20% 50V C652 1-162-282-31 CERAMIC 100PF 10% 50V C653 1-162-282-31 CERAMIC 100PF 10% 50V C654 1-102-942-00 CERAMIC 5.0PF 50V C655 1-104-665-11 ELECT 100uF 20.00% 16V C656 1-126-160-11 ELECT 1uF 20% 50V C659 1-137-372-11 MYLAR 0.022uF 5.00% 50V C660 1-126-160-11 ELECT 1uF 20% 50V C701 1-126-163-11 ELECT 4.7uF 20% 50V C702 1-162-282-31 CERAMIC 100PF 10% 50V C703 1-162-282-31 CERAMIC 100PF 10% 50V C704 1-102-942-00 CERAMIC 5.0PF 50V C706 1-126-160-11 ELECT 1uF 20% 50V C708 1-126-160-11 ELECT 1uF 20% 50V C709 1-137-372-11 MYLAR 0.022uF 5.00% 50V C715 1-104-665-11 ELECT 100uF 20.00% 16V C730 1-126-934-11 ELECT 220uF 20.00% 10V C732 1-164-159-11 CERAMIC 0.1uF 50V C751 1-126-163-11 ELECT 4.7uF 20% 50V C752 1-162-282-31 CERAMIC 100PF 10% 50V C753 1-162-282-31 CERAMIC 100PF 10% 50V C754 1-102-942-00 CERAMIC 5.0PF 50V C756 1-126-160-11 ELECT 1uF 20% 50V C758 1-126-160-11 ELECT 1uF 20% 50V C759 1-137-372-11 MYLAR 0.022uF 5.00% 50V C765 1-104-665-11 ELECT 100uF 20.00% 16V C801 1-136-169-00 MYLAR 0.22uF 5.00% 50V C802 1-136-169-00 MYLAR 0.22uF 5.00% 50V C803 1-126-256-11 ELECT 4700uF 20.00% 35V C804 1-126-256-11 ELECT 4700uF 20.00% 35V C807 1-104-664-11 ELECT 47uF 20.00% 25V C808 1-104-664-11 ELECT 47uF 20.00% 25V C809 1-126-160-11 ELECT 1uF 20% 50V C810 1-126-160-11 ELECT 1uF 20% 50V C811 1-126-942-61 ELECT 1000uF 20.00% 25V C812 1-126-941-11 ELECT 470uF 20.00% 25V C813 1-101-001-00 CERAMIC 0.001uF 50V C814 1-101-001-00 CERAMIC 0.001uF 50V C815 1-126-948-11 ELECT 100uF 20.00% 35V C816 1-126-967-11 ELECT 47uF 20.00% 50V C817 1-126-160-11 ELECT 1uF 20% 50V C818 1-104-664-11 ELECT 47uF 20.00% 25V CC08 1-162-282-31 CERAMIC 100PF 10% 50V CC09 1-162-282-31 CERAMIC 100PF 10% 50V CC10 1-162-282-31 CERAMIC 100PF 10% 50V CC58 1-162-282-31 CERAMIC 100PF 10% 50V CC59 1-162-282-31 CERAMIC 100PF 10% 50V CC60 1-162-282-31 CERAMIC 100PF 10% 50V CC401 1-162-282-31 CERAMIC 100PF 10% 50V CC403 1-162-282-31 CERAMIC 100PF 10% 50V CC405 1-162-282-31 CERAMIC 100PF 10% 50V CC451 1-162-282-31 CERAMIC 100PF 10% 50V CC453 1-162-282-31 CERAMIC 100PF 10% 50V CC455 1-162-282-31 CERAMIC 100PF 10% 50V CC463 1-162-282-31 CERAMIC 100PF 10% 50V < CONNECTOR > CN801 1-779-978-11 PIN, CONNECTOR 3P CNS301 1-569-321-11 SOCKET, CONNECTOR 15P CNS302 1-568-443-11 SOCKET, CONNECTOR 13P CNS800 1-691-770-11 PLUG (MICRO CONNECTOR) 8P CNS802 1-770-479-11 PLUG,CONNECTOR PIN(PC BOARD)4P < DIODE > D100 8-719-911-19 DIODE 1SS133T-72 D310 8-719-911-19 DIODE 1SS133T-72 D520 8-719-911-19 DIODE 1SS133T-72 D521 8-719-911-19 DIODE 1SS133T-72 D550 8-719-911-19 DIODE 1SS133T-72 D620 8-719-911-19 DIODE 1SS133T-72 D621 8-719-911-19 DIODE 1SS133T-72 D710 8-719-911-19 DIODE 1SS133T-72 D720 8-719-911-19 DIODE 1SS133T-72 D721 8-719-911-19 DIODE 1SS133T-72 D731 8-719-911-19 DIODE 1SS133T-72 D801 8-719-028-23 DIODE D3SBA20-4101 D810 8-719-024-99 DIODE 11ES2-NTA2B D811 8-719-024-99 DIODE 11ES2-NTA2B D812 8-719-986-54 DIODE HZS24-1LTA D813 8-719-109-85 DIODE MTZJ-T-72-5.1B D814 8-719-043-76 DIODE AK04V1 D820 8-719-024-99 DIODE 11ES2-NTA2B D821 8-719-024-99 DIODE 11ES2-NTA2B D822 8-719-024-99 DIODE 11ES2-NTA2B D823 8-719-024-99 DIODE 11ES2-NTA2B D850 8-719-911-19 DIODE 1SS133T-72 D853 8-719-911-19 DIODE 1SS133T-72 < EARTH > * G200 1-537-738-21 TERMINAL, EARTH * G201 1-537-738-21 TERMINAL, EARTH * G202 1-537-738-21 TERMINAL, EARTH < IC > IC100 8-759-537-31 IC M62447SP IC300 8-759-527-00 IC LV1035M IC302 8-759-636-74 IC M5218AP-22 IC401 8-759-000-48 IC MC14052BCP IC500 8-759-545-64 IC LC78212 MAIN www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks 22 IC501 8-759-502-33 IC SI-18752 IC502 8-759-636-74 IC M5218AP-22 IC503 8-759-636-74 IC M5218AP-22 IC601 8-759-502-33 IC SI-18752 IC651 8-759-502-33 IC SI-18752 IC701 8-759-502-33 IC SI-18752 IC751 8-759-502-33 IC SI-18752 IC801 8-759-605-00 IC M5F78M07L IC802 8-759-604-95 IC M5F79M07L IC803 8-759-701-59 IC M5F78M09L < JACK > J401 1-779-381-11 JACK, PIN 6P (5.1CH/DVD) J402 1-691-887-11 JACK, PIN 6P (DVD 2CH VIDEO2/TV/VIDEO) J404 1-774-785-11 JACK, PIN 1P (WOOFER MIX-OUT) < COIL > L301 1-410-509-11 INDUCTOR 10uH L507 1-420-872-00 COIL, AIR-CORE L607 1-420-872-00 COIL, AIR-CORE L657 1-420-872-00 COIL, AIR-CORE L707 1-420-872-00 COIL, AIR-CORE L757 1-420-872-00 COIL, AIR-CORE < TRANSISTOR > Q150 8-729-823-22 TRANSISTOR 2SC3576-AC Q151 8-729-823-22 TRANSISTOR 2SC3576-AC Q152 8-729-823-22 TRANSISTOR 2SC3576-AC Q153 8-729-823-22 TRANSISTOR 2SC3576-AC Q154 8-729-823-22 TRANSISTOR 2SC3576-AC Q155 8-729-823-22 TRANSISTOR 2SC3576-AC Q367 8-729-119-78 TRANSISTOR 2SC2785TP-HFE Q520 8-729-119-78 TRANSISTOR 2SC2785TP-HFE Q550 8-729-119-78 TRANSISTOR 2SC2785TP-HFE Q551 8-729-119-78 TRANSISTOR 2SC2785TP-HFE Q620 8-729-119-78 TRANSISTOR 2SC2785TP-HFE Q720 8-729-119-78 TRANSISTOR 2SC2785TP-HFE Q730 8-729-119-78 TRANSISTOR 2SC2785TP-HFE Q731 8-729-140-82 TRANSISTOR 2SA988TP-PAFAEA Q732 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA Q851 8-729-119-76 TRANSISTOR 2SA1115TP-F Q853 8-729-140-97 TRANSISTOR 2SB734-T-34 Q854 8-729-140-97 TRANSISTOR 2SB734-T-34 Q855 8-729-119-76 TRANSISTOR 2SA1115TP-F < RESISTOR > R100 1-249-433-11 CARBON 22K 5% 1/4W R101 1-249-433-11 CARBON 22K 5% 1/4W R103 1-249-433-11 CARBON 22K 5% 1/4W R104 1-247-807-31 CARBON 100 5% 1/4W R105 1-247-807-31 CARBON 100 5% 1/4W R106 1-247-879-11 CARBON 100K 5% 1/4W R107 1-247-807-31 CARBON 100 5% 1/4W R108 1-249-433-11 CARBON 22K 5% 1/4W R109 1-249-433-11 CARBON 22K 5% 1/4W R110 1-249-433-11 CARBON 22K 5% 1/4W R111 1-249-433-11 CARBON 22K 5% 1/4W R112 1-249-433-11 CARBON 22K 5% 1/4W R113 1-249-433-11 CARBON 22K 5% 1/4W R114 1-247-807-31 CARBON 100 5% 1/4W R115 1-247-807-31 CARBON 100 5% 1/4W R116 1-247-807-31 CARBON 100 5% 1/4W R117 1-249-437-11 CARBON 47K 5% 1/4W R150 1-249-417-11 CARBON 1K 5% 1/4W F R151 1-249-417-11 CARBON 1K 5% 1/4W F R152 1-249-417-11 CARBON 1K 5% 1/4W F R153 1-249-417-11 CARBON 1K 5% 1/4W F R154 1-249-417-11 CARBON 1K 5% 1/4W F R155 1-247-807-31 CARBON 100 5% 1/4W R156 1-249-441-11 CARBON 100K 5% 1/4W R157 1-249-441-11 CARBON 100K 5% 1/4W R158 1-249-441-11 CARBON 100K 5% 1/4W R159 1-249-441-11 CARBON 100K 5% 1/4W R160 1-249-441-11 CARBON 100K 5% 1/4W R161 1-249-437-11 CARBON 47K 5% 1/4W R162 1-249-433-11 CARBON 22K 5% 1/4W R163 1-249-433-11 CARBON 22K 5% 1/4W R164 1-249-433-11 CARBON 22K 5% 1/4W R165 1-249-433-11 CARBON 22K 5% 1/4W R166 1-249-433-11 CARBON 22K 5% 1/4W R167 1-249-425-11 CARBON 4.7K 5% 1/4W F R168 1-249-441-11 CARBON 100K 5% 1/4W R169 1-249-441-11 CARBON 100K 5% 1/4W R170 1-249-441-11 CARBON 100K 5% 1/4W R300 1-247-903-00 CARBON 1M 5% 1/4W R303 1-249-439-11 CARBON 68K 5% 1/4W R304 1-249-411-11 CARBON 330 5% 1/4W R306 1-249-436-11 CARBON 39K 5% 1/4W R307 1-249-429-11 CARBON 10K 5% 1/4W R308 1-249-429-11 CARBON 10K 5% 1/4W R309 1-249-421-11 CARBON 2.2K 5% 1/4W F R340 1-249-421-11 CARBON 2.2K 5% 1/4W F R341 1-249-421-11 CARBON 2.2K 5% 1/4W F R342 1-249-441-11 CARBON 100K 5% 1/4W R343 1-249-441-11 CARBON 100K 5% 1/4W R357 1-249-441-11 CARBON 100K 5% 1/4W R358 1-249-441-11 CARBON 100K 5% 1/4W R359 1-249-429-11 CARBON 10K 5% 1/4W R360 1-249-429-11 CARBON 10K 5% 1/4W R365 1-249-425-11 CARBON 4.7K 5% 1/4W F R374 1-249-429-11 CARBON 10K 5% 1/4W R375 1-249-429-11 CARBON 10K 5% 1/4W R381 1-247-807-31 CARBON 100 5% 1/4W R382 1-247-807-31 CARBON 100 5% 1/4W R383 1-247-807-31 CARBON 100 5% 1/4W 0R397 1-249-405-11 CARBON 100 5% 1/4W F R399 1-247-847-11 CARBON 4.7K 570 1/4W R401 1-249-417-11 CARBON 1K 5% 1/4W F R403 1-249-417-11 CARBON 1K 5% 1/4W F R405 1-249-417-11 CARBON 1K 5% 1/4W F R408 1-249-417-11 CARBON 1K 5% 1/4W F MAIN The components identified by mark 0 or dotted line with mark 0 are critical for safety. Replace only with part number specified. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks 23 R409 1-249-417-11 CARBON 1K 5% 1/4W F R410 1-249-417-11 CARBON 1K 5% 1/4W F R451 1-249-417-11 CARBON 1K 5% 1/4W F R453 1-249-417-11 CARBON 1K 5% 1/4W F R455 1-249-417-11 CARBON 1K 5% 1/4W F R458 1-249-417-11 CARBON 1K 5% 1/4W F R459 1-249-417-11 CARBON 1K 5% 1/4W F R460 1-249-417-11 CARBON 1K 5% 1/4W F R501 1-247-807-31 CARBON 100 5% 1/4W R502 1-249-433-11 CARBON 22K 5% 1/4W R504 1-249-433-11 CARBON 22K 5% 1/4W R507 1-249-389-11 CARBON 4.7 5% 1/4W F R508 1-249-437-11 CARBON 47K 5% 1/4W 0R509 1-249-393-11 CARBON 10 5% 1/4W F R512 1-249-441-11 CARBON 100K 5% 1/4W R513 1-249-429-11 CARBON 10K 5% 1/4W R514 1-249-429-11 CARBON 10K 5% 1/4W R515 1-249-419-11 CARBON 1.5K 5% 1/4W F R516 1-249-419-11 CARBON 1.5K 5% 1/4W F R517 1-249-429-11 CARBON 10K 5% 1/4W R518 1-249-429-11 CARBON 10K 5% 1/4W R519 1-249-863-11 CARBON 22K 5% 1/4W F R520 1-249-835-11 CARBON 1.5K 5% 1/4W F R521 1-249-425-11 CARBON 4.7K 5% 1/4W F R522 1-249-425-11 CARBON 4.7K 5% 1/4W F R523 1-249-433-11 CARBON 22K 5% 1/4W 0R540 1-249-401-11 CARBON 47 5% 1/4W F R550 1-249-429-11 CARBON 10K 5% 1/4W R551 1-249-441-11 CARBON 100K 5% 1/4W R552 1-247-843-11 CARBON 3.3K 5% 1/4W R553 1-249-429-11 CARBON 10K 5% 1/4W R554 1-249-416-11 CARBON 820 5% 1/4W F R555 1-249-425-11 CARBON 4.7K 5% 1/4W F R556 1-249-439-11 CARBON 68K 5% 1/4W R557 1-247-887-00 CARBON 220K 5% 1/4W R558 1-249-441-11 CARBON 100K 5% 1/4W R581 1-249-437-11 CARBON 47K 5% 1/4W R599 1-249-425-11 CARBON 4.7K 5% 1/4W F R601 1-247-807-31 CARBON 100 5% 1/4W R602 1-249-433-11 CARBON 22K 5% 1/4W R604 1-249-433-11 CARBON 22K 5% 1/4W R607 1-249-389-11 CARBON 4.7 5% 1/4W F R608 1-249-437-11 CARBON 47K 5% 1/4W 0R609 1-249-393-11 CARBON 10 5% 1/4W F R621 1-249-425-11 CARBON 4.7K 5% 1/4W F R622 1-249-425-11 CARBON 4.7K 5% 1/4W F R623 1-249-433-11 CARBON 22K 5% 1/4W 0R640 1-249-401-11 CARBON 47 5% 1/4W F R651 1-247-807-31 CARBON 100 5% 1/4W R652 1-249-433-11 CARBON 22K 5% 1/4W R654 1-249-433-11 CARBON 22K 5% 1/4W R657 1-249-389-11 CARBON 4.7 5% 1/4W F R658 1-249-437-11 CARBON 47K 5% 1/4W 0R659 1-249-393-11 CARBON 10 5% 1/4W F R701 1-247-807-31 CARBON 100 5% 1/4W R702 1-249-433-11 CARBON 22K 5% 1/4W R707 1-249-389-11 CARBON 4.7 5% 1/4W F R708 1-249-437-11 CARBON 47K 5% 1/4W 0R709 1-249-393-11 CARBON 10 5% 1/4W F R719 1-249-437-11 CARBON 47K 5% 1/4W R721 1-249-425-11 CARBON 4.7K 5% 1/4W F R722 1-249-425-11 CARBON 4.7K 5% 1/4W F R723 1-249-433-11 CARBON 22K 5% 1/4W R730 1-249-427-11 CARBON 6.8K 5% 1/4W F R731 1-249-429-11 CARBON 10K 5% 1/4W R732 1-249-435-11 CARBON 33K 5% 1/4W R733 1-249-429-11 CARBON 10K 5% 1/4W 0R740 1-249-401-11 CARBON 47 5% 1/4W F R742 1-249-433-11 CARBON 22K 5% 1/4W R750 1-249-417-11 CARBON 1K 5% 1/4W F R751 1-247-807-31 CARBON 100 5% 1/4W R752 1-249-433-11 CARBON 22K 5% 1/4W R754 1-249-433-11 CARBON 22K 5% 1/4W R757 1-249-389-11 CARBON 4.7 5% 1/4W F R758 1-249-437-11 CARBON 47K 5% 1/4W 0R759 1-249-393-11 CARBON 10 5% 1/4W F R760 1-249-407-11 CARBON 150 5% 1/4W F R761 1-249-407-11 CARBON 150 5% 1/4W F R762 1-249-407-11 CARBON 150 5% 1/4W F R763 1-249-407-11 CARBON 150 5% 1/4W F R764 1-249-407-11 CARBON 150 5% 1/4W F R765 1-249-407-11 CARBON 150 5% 1/4W F R766 1-249-407-11 CARBON 150 5% 1/4W F R767 1-249-407-11 CARBON 150 5% 1/4W F R768 1-249-407-11 CARBON 150 5% 1/4W F R769 1-249-437-11 CARBON 47K 5% 1/4W R770 1-249-407-11 CARBON 150 5% 1/4W F R810 1-249-386-11 CARBON 2.7 5% 1/6W F R811 1-249-386-11 CARBON 2.7 5% 1/6W F 0R812 1-249-409-11 CARBON 220 5% 1/4W F 0R850 1-249-408-11 CARBON 180 5% 1/4W F R851 1-249-433-11 CARBON 22K 5% 1/4W R852 1-249-429-11 CARBON 10K 5% 1/4W R855 1-249-433-11 CARBON 22K 5% 1/4W R856 1-249-425-11 CARBON 4.7K 5% 1/4W F R857 1-249-433-11 CARBON 22K 5% 1/4W R860 1-249-434-11 CARBON 27K 5% 1/4W R861 1-249-434-11 CARBON 27K 5% 1/4W R862 1-249-434-11 CARBON 27K 5% 1/4W R863 1-249-433-11 CARBON 22K 5% 1/4W R864 1-215-866-11 METAL OXIDE 330 5% 1W R865 1-249-437-11 CARBON 47K 5% 1/4W R866 1-249-437-11 CARBON 47K 5% 1/4W R901 1-249-425-11 CARBON 4.7K 5% 1/4W F < RELAY > RY301 1-755-267-11 RELAY RY501 1-755-170-11 RELAY (12V) RY601 1-755-170-11 RELAY (12V) RY701 1-755-170-11 RELAY (12V) MAIN The components identified by mark 0 or dotted line with mark 0 are critical for safety. Replace only with part number specified. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks 24 < TERMINAL > TM601 1-537-510-11 TERMINAL BOARD (SPEAKER)(6P)(SPEAKER REAR/CENTER) TM701 1-537-240-11 TERMINAL BOARD (CHECKER PIN)(SPEAKER FRONT) < VIBRATOR > X301 1-579-952-21 VIBRATOR, CERAMIC (8MHz) ************************************************************ 1-678-811-11 PRIMARY BOARD ************** ************************************************************ 1-678-814-11 PW.SW BOARD ************ < SWITCH > S200 1-762-875-21 SWITCH, KEYBOARD (?/1) ************************************************************ 1-678-812-11 SECONDARY BOARD **************** < RESISTOR > 0R801 1-249-381-11 CARBON 1 5% 1/4W F 0R802 1-249-381-11 CARBON 1 5% 1/4W F ************************************************************ A-4473-760-A STANDBY BOARD, COMPLETE ************************ 1-533-293-11 FUSE HOLDER < CAPACITOR > C920 1-161-494-00 CERAMIC 0.022uF 25V C921 1-161-494-00 CERAMIC 0.022uF 25V C950 1-126-767-11 ELECT 1000uF 20.00% 16V C951 1-164-159-11 CERAMIC 0.1uF 50V C952 1-126-960-11 ELECT 1uF 20.00% 50V C953 1-124-464-11 ELECT 0.22uF 20% 50V C954 1-126-964-11 ELECT 10uF 20.00% 50V C955 1-164-159-11 CERAMIC 0.1uF 50V C957 1-164-159-11 CERAMIC 0.1uF 50V < CONNECTOR > CNP902 1-564-321-00 PIN, CONNECTOR 2P < DIODE > D901 8-719-911-19 DIODE 1SS133T-72 D910 8-719-024-99 DIODE 11ES2-NTA2B D911 8-719-024-99 DIODE 11ES2-NTA2B D912 8-719-024-99 DIODE 11ES2-NTA2B D913 8-719-024-99 DIODE 11ES2-NTA2B D914 8-719-911-19 DIODE 1SS133T-72 D915 8-719-911-19 DIODE 1SS133T-72 < FUSE > 0F901 1-532-463-51 FUSE. TIME LAG 1A/250V < IC > IC950 8-759-333-83 IC NJM2103D < TRANSISTOR > Q901 8-729-119-78 TRANSISTOR 2SC2785TP-HFE Q951 8-729-026-68 TRANSISTOR 2SD2525(TP) < RESISTOR > R902 1-249-437-11 CARBON 47K 5% 1/4W R950 1-249-421-11 CARBON 2.2K 5% 1/4W F R951 1-249-425-11 CARBON 4.7K 5% 1/4W F R952 1-247-843-11 CARBON 3.3K 5% 1/4W R953 1-249-433-11 CARBON 22K 5% 1/4W R954 1-249-437-11 CARBON 47K 5% 1/4W R955 1-249-429-11 CARBON 10K 5% 1/4W R956 1-247-843-11 CARBON 3.3K 5% 1/4W R957 1-249-417-11 CARBON 1K 5% 1/4W F R958 1-249-421-11 CARBON 2.2K 5% 1/4W F R959 1-249-433-11 CARBON 22K 5% 1/4W R960 1-249-425-11 CARBON 4.7K 5% 1/4W F R970 1-249-399-11 CARBON 33 5% 1/4W F < RELAY > 0RY901 1-755-198-11 RELAY < TRANSFORMER > 0T902 1-431-739-11 TRANSFORMER, POWER ************************************************************ MISCELLANEOUS ************** 6 1-777-353-11 WIRE (FLAT TYPE) (15 CORE) 8 1-769-973-11 WIRE (FLAT TYPE) (13 CORE) FAN1 1-763-137-11 FAN, DC 0T900 1-431-979-11 TRANSFORMER, POWER 0PC900 1-777-071-21 CORD, POWER ************************************************************ ACCESSORIES & PACKING MATERIALS ******************************* 0 1-770-019-11 ADAPTOR, CONVERSION PLUG 3P (UK,HK) MAIN PRIMARY PW.SW SECONDARY STANDBY TA-VE170 Sony Corporation Audio Entertainment Group 9-929-501-11 2000G1661-1 Printed in Japan ©2000.7 Published by HA Quality Assurance Dept. The components identified by mark 0 or dotted line with mark 0 are critical for safety. Replace only with part number specified. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com
