TA-FE310R/FE510R AEP Model TA-FE310R/FE510R UK Model TA-FE310R SERVICE MANUAL INTEGRATED STEREO AMPLIFIER MICROFILM SPECIFICATIONS Photo : TA-FE510R Amplifier section DIN power output TA-FE510R: 80 W+80 W (4 ohms at 1 kHz) 60 W+60 W (8 ohms at 1 kHz) TA-FE310R: 55 W+55 W (4 ohms at 1 kHz) 45 W+45 W (8 ohms at 1 kHz) Frequency response PHONO (20 Hz-20 kHz): RIAA equalization curve ±0.5 dB TUNER, CD, AUX, TAPE1/DAT, TAPE2/MD: 7 Hz-70 kHz dB S/N (network A) PHONO: 80dB TUNER, CD, AUX, TAPE1/DAT, TAPE2/MD: 105 dB Output voltage/ impedance REC OUT: 200 mV, 1 kilohm PHONES: 5 mW (at 8 ohms) Speakers impedance: 4-16 ohms, 8-16 ohms (SPEAKERS A+B) Damping factor 80 (8 ohms, 1 kHz) General System Power amplifier: Pure-complementary SEPP OCL power amplifier with all stages directly coupled Preamplifier. Low-noise, equalizer amplifier Power requirements Models not supplied with a voltage selector: 220-230 V AC, 50/60 Hz Power consumption TA-FE510R: 160 W TA-FE310R: 120 W Dimensions (approx.) (w/h/d): 430×105×300 mm incl. projecting parts and controls Mass (approx.) TA-FE510R: 4.8 kg TA-FE310R: 4.3 kg Supplied accessories Remote commander (remote) (1) RM-S315 Sony batteries SUM-3 (NS) (2) Design and specifications are subject to change without notice. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com — 2 — 1. GENERAL 1-1. Index to Parts and Controls ................................................ 2 2. DIAGRAMS 2-1. Circuit Boards Location ..................................................... 3 2-2. IC Pin Function Description ............................................... 4 2-3. Schematic Diagram — Main Section — ............................ 5 2-4. Printed Wiring Boards — Main Section —........................ 7 2-5. Schematic Diagram — Panel Section —............................ 9 2-6. Printed Wiring Boards — Panel Section — ..................... 11 2-7. Schematic Diagram — Power Section — ........................ 13 3. EXPLODED VIEWS ................................................. 15 4. ELECTRICAL PARTS LIST ................................. 17 SAFETY-RELATED COMPONENT WARNING!! COMPONENTS IDENTIFIED BY MARK ! OR DOTTED LINE WITH MARK ! ON THE SCHEMATIC DIAGRAMS AND IN THE PARTS LIST ARE CRITICAL TO SAFE OPERATION. REPLACE THESE COMPONENTS WITH SONY PARTS WHOSE PART NUMBERS APPEAR AS SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUBLISHED BY SONY. SECTION 1 GENERAL 1-1. INDEX TO PARTS AND CONTROLS Front Panel Rear Panel 1 2 3 4 5 6 7 !™ !¡ 0 9 8 1 SYSTEM POWER switch 2 BASS control 3 TREBLE control 4 BALANCE control 5 INPUT SELECTOR indicators 6 INPUT SELECTOR 7 VOLUME control 8 PHONES jack 9 LOUDNESS switch !º TAPE 1 MONITOR switch (TA-FE510R only) !¡ SOURCE DIRECT switch !™ EON LINK switch (TA-FE510R only) This section is extracted from instruction manual. TABLE OF CONTENTS www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com SECTION 2 DIAGRAMS 2-1. CIRCUIT BOARDS LOCATION RELAY AC board SIRCS board HP board FUNCTION SW board CONTROL board EON board (FE510R) MAIN board AC board (AEP, Germany) SP board AC SW board RELAY DC board 2-2. IC PIN FUNCTION DESCRIPTION CONTROL BOARD IC801 TMP47C103N (INPUT CONTROL, LED DRIVE) Pin No. Pin Name I/O Function 1 X OUT O System clock. (4 MHz) 2 X IN I System clock. (4 MHz) 3 RESET I RESET input. 4 PMD I MODE select input. 5 VOL+ O Motor drive output (+). 6 VOL – O Motor drive output (–). 7 SW0 I Rotary switch input (CD). 8 SW1 I Rotary switch input (TUNER). 9 SW2 I Rotary switch input (PHONO). 10 EON I EON signal input. 11 PHONO O PHONO LED drive output. 12 TUNER O TUNER LED drive output. 13 CD O CD LED drive output. 14 GND – Ground. 15 AUX O AUX LED drive output. 16 DAT O TAPE “Z” LED drive output. 17 TAPE O TAPE “1” LED drive output. 18 MON O MONITOR output. 19 PRY O Power relay output. 20 PKY I Power key input. 21 MON I MONITOR input. 22 SIRCS I SIRCS input. 23 MUTE O Muting output. 24 SCE O Chip enable output. 25 SDT O Serial data output. 26 SCK O Serial clock output. 27 STOP I Stop input. 28 +3 V – +3 V power supply. — 3 — — 4 — www . x ia o y u 1 6 3 . c o m QQ 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com www. xiaoyu163. com QQ376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com www. xiaoyu163. com QQ376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com — 15 — SECTION 3 EXPLODED VIEWS Note: • -XX, -X mean standardized parts, so they may have some differences from the original one. • Items marked “*” are not stocked since they are seldom required for routine service. Some delay should be anticipated when ordering these items. • The mechanical parts with no reference number in the exploded views are not supplied. • Color Indication of Appearance Parts Example: KNOB, BALANCE (WHITE) The components identified by mark ! or dotted line with mark ! are critical for safety. Replace only with part number specified. • Hardware (# mark) list and accessories and packing materials are given in the last of this parts list. ↑ Cabinet’s Color (1) CASE, FRONT PANEL SECTION Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks 12 11 12 12 7 8 not supplied #2 6 5 3 4 2 1 supplied with S801 supplied with RV202 17 14 14 15 13 9 not supplied 9 16 #1 9 #1 10 #1 FE510R 9 supplied with J501 not supplied 17 1 X-4946-800-1 KNOB (VOL) ASSY (VOLUME)(BLACK) 1 X-4947-624-1 KNOB (VOL) ASSY (VOLUME)(SILVER) 2 X-4947-336-1 KNOB (DIA.47) ASSY (BLACK) (INPUT SELECTOR) 2 X-4947-625-1 KNOB (DIA.47) ASSY (SILVER) (INPUT SELECTOR) 3 4-980-204-01 KNOB (DIA.24)(BLACK) (BALANCE TONE) 3 4-980-204-11 KNOB (DIA.24)(SILVER)(BALANCE TONE) 4 X-4948-253-1 PANEL ASSY, FRONT (BLACK) 4 X-4948-254-1 PANEL ASSY, FRONT (BLACK) 4 X-4948-418-1 PANEL ASSY, FRONT (SILVER) 5 4-963-404-21 EMBLEM (5-A), SONY 6 4-980-199-01 BUTTON (POWER)(BLACK) 6 4-980-199-11 BUTTON (POWER)(SILVER) * 7 1-665-591-11 SIRCS BOARD * 8 1-665-595-11 AC SW BOARD 9 4-951-620-01 SCREW (2.6X8), +BVTP * 10 1-659-964-11 HP BOARD * 11 4-980-777-41 CASE (409526)(BLACK) * 11 4-980-777-61 CASE (409526)(SILVER) 12 3-704-366-01 SCREW (CASE)(M3X8)(BLACK) 12 3-704-366-71 SCREW (CASE)(M3X8)(SILVER) * 13 1-665-596-11 FUNCTION SW BOARD 14 1-769-983-11 WIRE (FLAT TYPE) (13 CORE) * 15 A-4398-021-A CONTROL BOARD, COMPLETE (FE510R) * 15 A-4398-017-A CONTROL BOARD, COMPLETE (FE310R) * 16 1-665-592-11 EON BOARD (FE510R) 17 4-980-189-01 KNOB (DIA. 6)(BLACK) 17 4-980-189-11 KNOB (DIA. 6)(SILVER) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com — 16 — #1 not supplied #4 #1 #1 #1 #1 #1 53 52 #3 not supplied T1 51 51 55 54 56 57 60 CN7 AEP, Germany UK 61 UK AEP, Germany CP1 CP1 #2 (2) CHASSIS SECTION Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks 59 CN8 CN9 #1 The components identified by mark ! or dotted line with mark ! are critical for safety. Replace only with part number specified. 51 X-4947-124-1 FOOT ASSY (F50150S)(SILVER) 51 X-4947-207-1 FOOT ASSY (F50150S)(BLACK) * 52 1-665-597-11 RELAY DC BOARD * 53 1-659-962-11 RELAY AC BOARD (UK) * 53 1-665-593-11 RELAY AC BOARD (AEP,Germany) * 54 A-4398-020-A MAIN BOARD, COMPLETE (FE510R) * 54 A-4398-016-A MAIN BOARD, COMPLETE (FE310R) * 55 3-703-244-00 BUSHING (2104), CORD 56 3-704-515-11 SCREW (BV/RING) * 57 4-989-459-02 PANEL, BACK (FE510R) * 57 4-989-462-02 PANEL, BACK (FE310R:AEP,Germany) * 57 4-989-462-12 PANEL, BACK (FE310R:UK) * 59 1-665-599-11 SP BOARD * 60 1-665-598-11 AC BOARD (AEP,Germany) 61 4-956-370-12 BAND, PLUG FIXED (UK) !CN7 1-526-794-11 OUTLET, AC (AEP,Germany) !CN8 1-526-794-11 OUTLET, AC (AEP,Germany) !CN9 1-526-794-11 OUTLET, AC (AEP,Germany) !CP1 1-575-651-21 CORD, POWER (AEP,Germany) !CP1 1-696-586-11 CORD, POWER (UK) !T1 1-429-448-11 TRANSFORMER, POWER (FE510R) !T1 1-429-452-11 TRANSFORMER, POWER (FE310R) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com Note: • Due to standardization, replacements in the parts list may be different from the parts specified in the diagrams or the components used on the set. • -XX, -X mean standardized parts, so they may have some difference from the original one. • Items marked “*” are not stocked since they are seldom required for routine service. Some delay should be anticipated when ordering these items. • CAPACITORS: uF: µF The components identified by mark ! or dotted line with mark ! are critical for safety. Replace only with part number specified. • RESISTORS All resistors are in ohms. METAL: metal-film resistor METAL OXIDE: Metal Oxide-film resistor F: nonflammable • COILS uH: µH • SEMICONDUCTORS In each case, u: µ, for example: uA...: µA... , uPA... , µPA... , uPB... , µPB... , uPC... , µPC... , uPD..., µPD... When indicating parts by reference number, please include the board naame. Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks — 17 — SECTION 4 ELECTRICAL PARTS LIST * 1-665-598-11 AC BOARD (AEP,Germany) ******** 1-533-293-11 FUSE HOLDER < CONNECTOR > !CN7 1-526-794-11 OUTLET, AC !CN8 1-526-794-11 OUTLET, AC !CN9 1-526-794-11 OUTLET, AC < FUSE > !F2 1-532-464-51 FUSE,TIME LAG 2.5A/250V ************************************************************ * 1-665-595-11 AC SW BOARD ************ < CONNECTOR > * CN953 1-564-506-11 PLUG, CONNECTOR 3P CN955 1-564-505-11 PLUG, CONNECTOR 2P < SWITCH > S1 1-554-920-11 SWITCH, PUSH (AC POWER)(1 KEY) ************************************************************ * A-4398-017-A CONTROL BOARD, COMPLETE (FE310R) ************************ * A-4398-021-A CONTROL BOARD, COMPLETE (FE510R) ************************ < CAPACITOR > C201 1-136-153-00 FILM 0.01uF 5% 50V C202 1-136-165-00 FILM 0.1uF 5% 50V C203 1-130-477-00 MYLAR 0.0033uF 5% 50V C204 1-136-159-00 FILM 0.033uF 5% 50V C205 1-130-473-00 MYLAR 0.0015uF 5% 50V C251 1-136-153-00 FILM 0.01uF 5% 50V C252 1-136-165-00 FILM 0.1uF 5% 50V C253 1-130-477-00 MYLAR 0.0033uF 5% 50V C254 1-136-159-00 FILM 0.033uF 5% 50V C255 1-130-473-00 MYLAR 0.0015uF 5% 50V C801 1-126-096-11 ELECT 10uF 20% 35V C802 1-126-916-11 ELECT 1000uF 20% 6.3V C803 1-164-159-11 CERAMIC 0.1uF 50V C806 1-162-294-31 CERAMIC 0.001uF 10% 50V C807 1-126-096-11 ELECT 10uF 20% 35V C808 1-124-463-00 ELECT 0.1uF 20% 50V C809 1-126-301-11 ELECT 1uF 20% 50V < CONNECTOR > * CN801 1-568-832-11 SOCKET, CONNECTOR 13P CN802 1-562-087-00 SOCKET, CONNECTOR 4P CN804 1-562-087-00 SOCKET, CONNECTOR 4P CN806 1-774-913-11 PIN, CONNECTOR 4P * CN814 1-568-832-11 SOCKET, CONNECTOR 13P < DIODE > D801 8-719-985-59 DIODE HZS4CLL D802 8-719-987-63 DIODE 1N4148M D803 8-719-987-63 DIODE 1N4148M D804 8-719-987-63 DIODE 1N4148M D805 8-719-987-63 DIODE 1N4148M D806 8-719-987-63 DIODE 1N4148M D807 8-719-313-50 DIODE SEL6810A-TH12 (SOURCE DIRECT) D808 8-719-313-50 DIODE SEL6810A-TH12 (PHONO) D809 8-719-313-50 DIODE SEL6810A-TH12 (TUNER) D810 8-719-313-50 DIODE SEL6810A-TH12 (CD) D811 8-719-313-50 DIODE SEL6810A-TH12 (AUX) D812 8-719-313-50 DIODE SEL6810A-TH12 (TAPE2/MD) D813 8-719-313-50 DIODE SEL6810A-TH12 (TAPE1/DAT) D814 8-719-987-63 DIODE 1N4148M D816 8-719-987-63 DIODE 1N4148M D817 8-719-987-63 DIODE 1N4148M D819 8-719-987-63 DIODE 1N4148M D820 8-719-024-99 DIODE 11ES2-NTA2B D823 8-719-313-50 DIODE SEL6810A-TH12 (TAPE1 MONITOR) (FE510R) < IC > IC801 8-759-392-41 IC TMP47C103N IC802 8-759-962-08 IC BA6208 < TRANSISTOR > Q801 8-729-119-78 TRANSISTOR 2SC2785-HFE Q802 8-729-620-05 TRANSISTOR 2SC2603-EF Q803 8-729-661-98 TRANSISTOR RT1P141SK-TP (FE510R) Q804 8-729-661-98 TRANSISTOR RT1P141SK-TP Q806 8-729-620-05 TRANSISTOR 2SC2603-EF Q807 8-729-620-05 TRANSISTOR 2SC2603-EF Q808 8-729-620-05 TRANSISTOR 2SC2603-EF Q810 8-729-661-94 TRANSISTOR RT1N141SK-TP Q811 8-729-661-94 TRANSISTOR RT1N141SK-TP < RESISTOR > R201 1-249-433-11 CARBON 22K 5% 1/4W R202 1-249-421-11 CARBON 2.2K 5% 1/4W F R203 1-249-427-11 CARBON 6.8K 5% 1/4W F R204 1-249-415-11 CARBON 680 5% 1/4W F R205 1-249-421-11 CARBON 2.2K 5% 1/4W F AC AC SW CONTROL www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks — 18 — R206 1-249-441-11 CARBON 100K 5% 1/4W R208 1-249-439-11 CARBON 68K 5% 1/4W R251 1-249-433-11 CARBON 22K 5% 1/4W R252 1-249-421-11 CARBON 2.2K 5% 1/4W F R253 1-249-427-11 CARBON 6.8K 5% 1/4W F R254 1-249-415-11 CARBON 680 5% 1/4W F R255 1-249-421-11 CARBON 2.2K 5% 1/4W F R256 1-249-441-11 CARBON 100K 5% 1/4W R258 1-249-439-11 CARBON 68K 5% 1/4W R317 1-247-750-11 CARBON 680 5% 1/2W F R367 1-247-750-11 CARBON 680 5% 1/2W F R801 1-249-411-11 CARBON 330 5% 1/4W R802 1-247-807-31 CARBON 100 5% 1/4W R803 1-249-429-11 CARBON 10K 5% 1/4W R804 1-249-429-11 CARBON 10K 5% 1/4W R805 1-249-425-11 CARBON 4.7K 5% 1/4W F R806 1-247-843-11 CARBON 3.3K 5% 1/4W R807 1-247-843-11 CARBON 3.3K 5% 1/4W R808 1-249-429-11 CARBON 10K 5% 1/4W R809 1-249-429-11 CARBON 10K 5% 1/4W R810 1-249-429-11 CARBON 10K 5% 1/4W R811 1-249-429-11 CARBON 10K 5% 1/4W R812 1-249-399-11 CARBON 33 5% 1/4W F R814 1-249-413-11 CARBON 470 5% 1/4W F (FE510R) R815 1-249-429-11 CARBON 10K 5% 1/4W R816 1-249-429-11 CARBON 10K 5% 1/4W R817 1-249-429-11 CARBON 10K 5% 1/4W R818 1-249-429-11 CARBON 10K 5% 1/4W R819 1-249-429-11 CARBON 10K 5% 1/4W R820 1-249-429-11 CARBON 10K 5% 1/4W R821 1-249-429-11 CARBON 10K 5% 1/4W R822 1-249-429-11 CARBON 10K 5% 1/4W R823 1-249-437-11 CARBON 47K 5% 1/4W R824 1-249-441-11 CARBON 100K 5% 1/4W R826 1-249-399-11 CARBON 33 5% 1/4W F R827 1-249-393-11 CARBON 10 5% 1/4W F (FE510R) R828 1-249-429-11 CARBON 10K 5% 1/4W R829 1-249-429-11 CARBON 10K 5% 1/4W R830 1-249-429-11 CARBON 10K 5% 1/4W R834 1-249-413-11 CARBON 470 5% 1/4W F R837 1-249-407-11 CARBON 150 5% 1/4W F < VARIABLE RESISTOR > RV201 1-223-396-11 RES, VAR, CARBON 100K/100K (BALANCE) RV202 1-241-426-11 RES, VAR, CARBON 100KX2 (VOLUME) RV203 1-223-397-11 RES, VAR, CARBON 100K/100K (BASS) RV204 1-223-397-11 RES, VAR, CARBON 100K/100K (TREBLE) < SWITCH > S201 1-571-112-21 SWITCH, PUSH (1 KEY)(LOUDNESS) S202 1-571-828-11 SWITCH, PUSH (1 KEY)(SOURCE DIRECT) S802 1-762-750-11 SWITCH, TACTILE (TAPE1 MONITOR)(FE510R) < VIBRATOR > X801 1-577-358-21 VIBRATOR, CERAMIC 4MHz ************************************************************ * 1-665-592-11 EON BOARD (FE510R) ********** < CONNECTOR > CN810 1-564-506-11 PLUG, CONNECTOR 3P < DIODE > D821 8-719-313-50 DIODE SEL6810A-TH12 (EON LINE) < TRANSISTOR > Q809 8-729-661-94 TRANSISTOR RT1N141SK-TP Q812 8-729-620-05 TRANSISTOR 2SC2603-EF Q813 8-729-620-05 TRANSISTOR 2SC2603-EF < RESISTOR > R831 1-249-399-11 CARBON 33 5% 1/4W F R835 1-249-429-11 CARBON 10K 5% 1/4W R836 1-249-425-11 CARBON 4.7K 5% 1/4W F R838 1-249-407-11 CARBON 150 5% 1/4W F < SWITCH > S803 1-571-112-21 SWITCH, PUSH (1 KEY) (EON LINE) ************************************************************ * 1-665-596-11 FUNCTION SW BOARD ****************** < CONNECTOR > CN805 1-774-913-11 PIN, CONNECTOR 4P < SWITCH > S801 1-692-974-11 SWITCH, ROTARY (INPUT SELECTOR) ************************************************************ * 1-659-964-11 HP BOARD ********* < CONNECTOR > CN803 1-560-941-11 PIN, CONNECTOR 4P < JACK > J501 1-774-933-11 JACK (LARGE TYPE)(PHONES) (FE310R/FE510R:AEP (BLACK)) J501 1-580-903-11 JACK, LARGE TYPE (PHONES) (FE510R:AEP (SILVER)) ************************************************************ * A-4398-016-A MAIN BOARD, COMPLETE (FE310R) ********************* * A-4398-020-A MAIN BOARD, COMPLETE (FE510R) ********************* < CAPACITOR > C101 1-162-282-31 CERAMIC 100PF 10% 50V C102 1-162-286-31 CERAMIC 220PF 10% 50V C103 1-126-963-11 ELECT 4.7uF 20% 50V C104 1-126-967-11 ELECT 47uF 20% 16V CONTROL EON FUNCTION SW HP MAIN www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks — 19 — C105 1-162-282-31 CERAMIC 100PF 10% 50V C106 1-130-480-00 MYLAR 0.0056uF 5% 50V C107 1-130-473-00 MYLAR 0.0015uF 5% 50V C108 1-126-964-11 ELECT 10uF 20% 50V C109 1-126-964-11 ELECT 10uF 20% 50V C112 1-162-294-31 CERAMIC 0.001uF 10% 50V C114 1-162-306-11 CERAMIC 0.01uF 20% 16V C115 1-126-963-11 ELECT 4.7uF 20% 50V C151 1-162-282-31 CERAMIC 100PF 10% 50V C152 1-162-286-31 CERAMIC 220PF 10% 50V C153 1-126-963-11 ELECT 4.7uF 20% 50V C154 1-126-967-11 ELECT 47uF 20% 16V C155 1-162-282-31 CERAMIC 100PF 10% 50V C156 1-130-480-00 MYLAR 0.0056uF 5% 50V C157 1-130-473-00 MYLAR 0.0015uF 5% 50V C158 1-126-964-11 ELECT 10uF 20% 50V C301 1-126-964-11 ELECT 10uF 20% 50V C302 1-162-290-31 CERAMIC 470PF 10% 50V C303 1-162-282-31 CERAMIC 100PF 10% 50V C305 1-126-933-11 ELECT 100uF 20% 10V C306 1-126-967-11 ELECT 47uF 20% 50V C307 1-126-965-11 ELECT 22uF 20% 50V C308 1-126-965-11 ELECT 22uF 20% 50V C309 1-126-965-11 ELECT 22uF 20% 50V C310 1-126-968-11 ELECT 100uF 20% 50V (FE310R) C310 1-126-969-11 ELECT 220uF 20% 50V (FE510R) C311 1-136-495-11 FILM 0.068uF 5% 50V C312 1-136-495-11 FILM 0.068uF 5% 50V C313 1-126-967-11 ELECT 47uF 20% 16V C314 1-162-195-31 CERAMIC 4.7PF 10% 50V C315 1-126-968-11 ELECT 100uF 20% 50V (FE310R) C315 1-126-969-11 ELECT 220uF 20% 50V (FE510R) C351 1-126-964-11 ELECT 10uF 20% 50V C352 1-162-290-31 CERAMIC 470PF 10% 50V C353 1-162-282-31 CERAMIC 100PF 10% 50V C355 1-126-933-11 ELECT 100uF 20% 10V C356 1-126-967-11 ELECT 47uF 20% 50V C361 1-136-495-11 FILM 0.068uF 5% 50V C362 1-136-495-11 FILM 0.068uF 5% 50V C363 1-126-967-11 ELECT 47uF 20% 16V C364 1-162-195-31 CERAMIC 4.7PF 10% 50V C601 1-126-961-11 ELECT 2.2uF 20% 50V C602 1-126-923-11 ELECT 220uF 20% 10V C603 1-126-967-11 ELECT 47uF 20% 16V C812 1-164-159-11 CERAMIC 0.1uF 50V (FE510R) C900 1-136-153-00 FILM 0.01uF 5% 50V C903 1-126-224-11 ELECT 4700uF 20% 42V (FE310R) C903 1-126-307-11 ELECT 6800uF 20% 50V (FE510R) MAIN C904 1-126-224-11 ELECT 4700uF 20% 42V (FE310R) C904 1-126-307-11 ELECT 6800uF 20% 50V (FE510R) C905 1-126-948-11 ELECT 100uF 20% 35V (FE310R) C905 1-126-968-11 ELECT 100uF 20% 50V (FE510R) C906 1-126-948-11 ELECT 100uF 20% 35V (FE310R) C906 1-126-968-11 ELECT 100uF 20% 50V (FE510R) C907 1-164-097-11 CERAMIC 0.022uF 50V C908 1-126-967-11 ELECT 47uF 20% 16V C909 1-126-967-11 ELECT 47uF 20% 16V C910 1-126-933-11 ELECT 100uF 20% 16V C911 1-126-933-11 ELECT 100uF 20% 16V C915 1-126-933-11 ELECT 100uF 20% 16V C916 1-126-963-11 ELECT 4.7uF 20% 50V < CONNECTOR > * CN811 1-568-832-11 SOCKET, CONNECTOR 13P CN812 1-564-506-11 PLUG, CONNECTOR 3P (FE510R) CN813 1-566-212-11 PIN, CONNECTOR 3P (FE510R) * CN815 1-568-832-11 SOCKET, CONNECTOR 13P * CN951 1-564-104-00 PIN, CONNECTOR (B3P-VH) 3P CN952 1-691-768-11 PLUG (MICRO CONNECTOR) 6P < DIODE > D101 8-719-987-63 DIODE 1N4148M (FE510R) D301 8-719-987-63 DIODE 1N4148M D302 8-719-987-63 DIODE 1N4148M D351 8-719-987-63 DIODE 1N4148M D352 8-719-987-63 DIODE 1N4148M D601 8-719-987-63 DIODE 1N4148M D902 8-719-001-64 DIODE UZL-12L2 D903 8-719-001-64 DIODE UZL-12L2 < TERMINAL > * EB1 1-537-738-21 TERMINAL, EARTH < IC > IC101 8-759-805-13 IC LC7821 IC102 8-759-184-02 IC NJM2068L-D IC301 8-749-900-24 IC STK-4162MK2 (FE310R) IC301 8-749-941-91 IC STK-4191V (FE510R) IC601 8-759-111-68 IC uPC1237HA IC901 8-759-701-75 IC NJM7805FA < JACK > J101 1-774-411-11 JACK, PIN 6P (PHONO,TUNER,CD) J102 1-573-028-31 JACK, PIN 4P (AUX,TAPE2/MD(REC OUT) J103 1-770-015-11 JACK, PIN 6P (TAPE1/DAT,TAPE2/MD(IN)) < COIL > L301 1-420-872-00 COIL, AIR-CORE L351 1-420-872-00 COIL, AIR-CORE www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks — 20 — < TRANSISTOR > Q101 8-729-141-26 TRANSISTOR 2SC3622A-LK Q102 8-729-119-77 TRANSISTOR 2SA1175-FEK Q103 8-729-620-05 TRANSISTOR 2SC2603-EF (FE510R) Q104 8-729-620-05 TRANSISTOR 2SC2603-EF Q151 8-729-141-26 TRANSISTOR 2SC3622A-LK Q301 8-729-140-82 TRANSISTOR 2SA988-PAFAEA Q351 8-729-140-82 TRANSISTOR 2SA988-PAFAEA Q901 8-729-119-78 TRANSISTOR 2SC2785-HFE Q902 8-729-201-53 TRANSISTOR 2SA1015-GR Q903 8-729-620-05 TRANSISTOR 2SC2603-EF < RESISTOR > R101 1-249-418-11 CARBON 1.2K 5% 1/4W F R102 1-249-411-11 CARBON 330 5% 1/4W R104 1-249-437-11 CARBON 47K 5% 1/4W R105 1-249-416-11 CARBON 820 5% 1/4W F R106 1-247-897-11 CARBON 560K 5% 1/4W R107 1-249-437-11 CARBON 47K 5% 1/4W R108 1-249-441-11 CARBON 100K 5% 1/4W R109 1-249-409-11 CARBON 220 5% 1/4W F R110 1-249-417-11 CARBON 1K 5% 1/4W F R111 1-249-417-11 CARBON 1K 5% 1/4W F R112 1-249-417-11 CARBON 1K 5% 1/4W F R113 1-249-417-11 CARBON 1K 5% 1/4W F R114 1-249-417-11 CARBON 1K 5% 1/4W F R115 1-249-417-11 CARBON 1K 5% 1/4W F R116 1-249-417-11 CARBON 1K 5% 1/4W F R117 1-249-417-11 CARBON 1K 5% 1/4W F R118 1-249-427-11 CARBON 6.8K 5% 1/4W F R119 1-249-425-11 CARBON 4.7K 5% 1/4W F R120 1-249-409-11 CARBON 220 5% 1/4W F R121 1-249-437-11 CARBON 47K 5% 1/4W R122 1-249-419-11 CARBON 1.5K 5% 1/4W F R123 1-249-427-11 CARBON 6.8K 5% 1/4W F R124 1-249-425-11 CARBON 4.7K 5% 1/4W F (FE510R) R125 1-249-441-11 CARBON 100K 5% 1/4W R126 1-249-441-11 CARBON 100K 5% 1/4W R151 1-249-418-11 CARBON 1.2K 5% 1/4W F R152 1-249-411-11 CARBON 330 5% 1/4W R154 1-249-437-11 CARBON 47K 5% 1/4W R155 1-249-416-11 CARBON 820 5% 1/4W F R156 1-247-897-11 CARBON 560K 5% 1/4W R157 1-249-437-11 CARBON 47K 5% 1/4W R158 1-249-441-11 CARBON 100K 5% 1/4W R159 1-249-409-11 CARBON 220 5% 1/4W F R160 1-249-417-11 CARBON 1K 5% 1/4W F R161 1-249-417-11 CARBON 1K 5% 1/4W F R162 1-249-417-11 CARBON 1K 5% 1/4W F R163 1-249-417-11 CARBON 1K 5% 1/4W F R164 1-249-417-11 CARBON 1K 5% 1/4W F R165 1-249-417-11 CARBON 1K 5% 1/4W F R166 1-249-417-11 CARBON 1K 5% 1/4W F R167 1-249-417-11 CARBON 1K 5% 1/4W F R168 1-249-427-11 CARBON 6.8K 5% 1/4W F R176 1-249-441-11 CARBON 100K 5% 1/4W R207 1-249-425-11 CARBON 4.7K 5% 1/4W F R257 1-249-425-11 CARBON 4.7K 5% 1/4W F R301 1-249-439-11 CARBON 68K 5% 1/4W R302 1-249-417-11 CARBON 1K 5% 1/4W F R303 1-249-415-11 CARBON 680 5% 1/4W F R304 1-249-439-11 CARBON 68K 5% 1/4W R305 1-249-421-11 CARBON 2.2K 5% 1/4W F (FE310R) R305 1-247-843-11 CARBON 3.3K 5% 1/4W (FE510R) R306 1-260-103-11 CARBON 2.2K 5% 1/2W (FE310R) R306 1-260-105-11 CARBON 3.3K 5% 1/2W (FE510R) R307 1-249-405-11 CARBON 100 5% 1/4W F R308 1-260-099-11 CARBON 1K 5% 1/2W R309 1-260-099-11 CARBON 1K 5% 1/2W R310 1-249-405-11 CARBON 100 5% 1/4W F R312 1-249-419-11 CARBON 1.5K 5% 1/4W F R313 1-249-431-11 CARBON 15K 5% 1/4W !R314 1-217-151-00 RES, METAL PLATE 0.22 R315 1-249-437-11 CARBON 47K 5% 1/4W R316 1-247-727-11 CARBON 10 5% 1/2W R318 1-249-393-11 CARBON 10 5% 1/4W F R320 1-249-385-11 CARBON 2.2 5% 1/6W F R321 1-249-385-11 CARBON 2.2 5% 1/6W F R322 1-249-385-11 CARBON 2.2 5% 1/6W F R351 1-249-439-11 CARBON 68K 5% 1/4W R352 1-249-417-11 CARBON 1K 5% 1/4W F R353 1-249-415-11 CARBON 680 5% 1/4W F R354 1-249-439-11 CARBON 68K 5% 1/4W R355 1-249-421-11 CARBON 2.2K 5% 1/4W F (FE310R) R355 1-247-843-11 CARBON 3.3K 5% 1/4W (FE510R) R356 1-260-103-11 CARBON 2.2K 5% 1/2W (FE310R) R356 1-260-105-11 CARBON 3.3K 5% 1/2W (FE510R) R362 1-249-419-11 CARBON 1.5K 5% 1/4W F R363 1-249-431-11 CARBON 15K 5% 1/4W !R364 1-217-151-00 RES, METAL PLATE 0.22 R365 1-249-439-11 CARBON 68K 5% 1/4W R366 1-247-727-11 CARBON 10 5% 1/2W R368 1-249-393-11 CARBON 10 5% 1/4W F R601 1-247-745-11 CARBON 330 5% 1/2W F (FE310R) R601 1-247-747-11 CARBON 470 5% 1/2W (FE510R) R602 1-247-745-11 CARBON 330 5% 1/2W F (FE310R) R602 1-247-747-11 CARBON 470 5% 1/2W (FE510R) R603 1-249-417-11 CARBON 1K 5% 1/4W F R604 1-249-441-11 CARBON 100K 5% 1/4W R605 1-249-439-11 CARBON 68K 5% 1/4W R606 1-249-431-11 CARBON 15K 5% 1/4W R607 1-247-756-11 CARBON 2.2K 5% 1/2W R608 1-247-756-11 CARBON 2.2K 5% 1/2W MAIN The components identified by mark ! or dotted line with mark ! are critical for safety. Replace only with part number specified. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks — 21 — R832 1-249-393-11 CARBON 10 5% 1/4W F (FE510R) R902 1-247-750-11 CARBON 680 5% 1/2W F R903 1-247-750-11 CARBON 680 5% 1/2W F R904 1-247-750-11 CARBON 680 5% 1/2W F R905 1-247-750-11 CARBON 680 5% 1/2W F R907 1-247-752-11 CARBON 1K 5% 1/2W R908 1-247-752-11 CARBON 1K 5% 1/2W R910 1-249-429-11 CARBON 10K 5% 1/4W R912 1-249-429-11 CARBON 10K 5% 1/4W R916 1-249-419-11 CARBON 1.5K 5% 1/4W F < RELAY > RY101 1-515-614-11 RELAY (FE510R) RY601 1-515-920-11 RELAY (24V) ************************************************************ * 1-659-962-11 RELAY AC BOARD (UK) ************** * 1-665-593-11 RELAY AC BOARD (AEP,Germany) ************** 1-533-293-11 FUSE HOLDER < CONNECTOR > * CN1 1-580-230-31 PIN, CONNECTOR (PC BOARD) 2P CN2 1-564-321-00 PIN, CONNECTOR 2P (AEP,Germany) * CN954 1-564-506-11 PLUG, CONNECTOR 3P (AEP,Germany) < DIODE > D911 8-719-987-63 DIODE 1N4148M (AEP,Germany) < FUSE > !F1 1-532-503-51 FUSE, TIME LAG 1.6A/250V < RELAY > !RY1 1-755-018-11 RELAY (AEP,Germany) < TRANSFORMER > !T1 1-429-448-11 TRANSFORMER, POWER (FE510R) !T1 1-429-452-11 TRANSFORMER, POWER (FE310R) ************************************************************ * 1-665-597-11 RELAY DC BOARD ************** < CAPACITOR > C901 1-106-379-12 MYLAR 0.033uF 5% 200V C902 1-106-379-12 MYLAR 0.033uF 5% 200V C912 1-136-153-00 FILM 0.01uF 5% 50V C913 1-126-941-11 ELECT 470uF 20% 25V < CONNECTOR > * CN901 1-564-104-00 PIN, CONNECTOR (B3P-VH) 3P CN902 1-691-768-11 PLUG (MICRO CONNECTOR) 6P * CN904 1-564-506-11 PLUG, CONNECTOR 3P < DIODE > D901 8-719-028-23 DIODE D3SBA20-4101 (FE310R) D901 8-719-302-37 DIODE RBV-602 (FE510R) D904 8-719-024-99 DIODE 11ES2-NTA2B D905 8-719-024-99 DIODE 11ES2-NTA2B D906 8-719-024-99 DIODE 11ES2-NTA2B D907 8-719-024-99 DIODE 11ES2-NTA2B D908 8-719-024-99 DIODE 11ES2-NTA2B D909 8-719-024-99 DIODE 11ES2-NTA2B D910 8-719-987-63 DIODE 1N4148M < RESISTOR > R901 1-249-451-11 CARBON 2.2 5% 1/4W R913 1-249-431-11 CARBON 15K 5% 1/4W (FE310R) R913 1-249-433-11 CARBON 22K 5% 1/4W (FE510R) < RELAY > RY901 1-755-018-11 RELAY RY902 1-755-018-11 RELAY ************************************************************ * 1-665-591-11 SIRCS BOARD *********** < CONNECTOR > CN807 1-562-087-00 SOCKET, CONNECTOR 4P < DIODE > D822 8-719-313-48 DIODE SEL6210S-TH12 (STANDBY) < IC > IC803 8-759-373-49 IC NJL54H400 < RESISTOR > R833 1-249-421-11 CARBON 2.2K 5% 1/4W F ************************************************************ * 1-665-599-11 SP BOARD ******** < TERMINAL > TM301 1-694-261-11 TERMINAL BOARD (SP)(SPEAKERS) ************************************************************ MISCELLANEOUS ************* 14 1-769-983-11 WIRE (FLAT TYPE) (13 CORE) !CN7 1-526-794-11 OUTLET, AC (AEP,Germany) !CN8 1-526-794-11 OUTLET, AC (AEP,Germany) !CN9 1-526-794-11 OUTLET, AC (AEP,Germany) !CP1 1-575-651-21 CORD, POWER (AEP,Germany) !CP1 1-696-586-11 CORD, POWER (UK) !T1 1-429-448-11 TRANSFORMER, POWER (FE510R) !T1 1-429-452-11 TRANSFORMER, POWER (FE310R) ************************************************************ MAIN The components identified by mark ! or dotted line with mark ! are critical for safety. Replace only with part number specified. RELAY AC RELAY DC SIRCS SP www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks — 22 — ACCESSORIES & PACKING MATERIALS ******************************* 1-473-655-11 REMOTE COMMANDER (RM-S315) 3-860-499-11 MANUAL, INSTRUCTION (ENGLISH,FRENCH,SPANISH,PORTUGUESE) 3-860-499-21 MANUAL, INSTRUCTION (GERMAN,DUTCH,SWEDISH,ITALIAN) (AEP,Germany) 4-981-643-01 COVER, BATTERY (FOR RM-S315) ************************************************************ ************** HARDWARE LIST ************** #1 7-685-646-79 SCREW +BVTP 3X8 TYPE2 IT-3 #2 7-685-872-09 SCREW +BVTT 3X8 (S) #3 7-685-650-79 SCREW +BVTP 3X16 TYPE2 IT-3 #4 7-685-880-09 SCREW +BVTT 4X6 (S) TA-FE310R/FE510R Sony Corporation Hame A&V Products Company 9-960-956-11 97E167553-1 Printed in Hangary © 1997.5 Published by General Engineering Dept. (Shibaura) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com
