– 1 – MICROFILM AEP Model SPECIFICATIONS SERVICE MANUAL INTEGRATED STEREO AMPLIFIER TA-FB720R/FB820R Photo : TA-FB820R www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 2 – SAFETY-RELATED COMPONENT WARNING !! COMPONENTS IDENTIFIED BY MARK ! OR DOTTED LINE WITH MARK ! ON THE SCHEMATIC DIAGRAMS AND IN THE PARTS LIST ARE CRITICAL TO SAFE OPERATION. REPLACE THESE COMPONENTS WITH SONY PARTS WHOSE PART NUMBERS APPEAR AS SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUBLISHED BY SONY. TABLE OF CONTENTS 1. GENERAL .......................................................................... 3 2. ELECTRICAL ADJUSTMENT ..................................... 4 3. DIAGRAMS 3-1. Circuit Boards Location ........................................................ 5 3-2. Schematic Diagram – Input Section – .................................. 7 3-3. Printed Wiring Board – Input Section – ................................ 9 3-4. Schematic Diagram – Main Section – ................................ 11 3-5. Printed Wiring Board – Main Section – .............................. 13 3-6. Schematic Diagram – Panel Section – ................................ 15 3-7. Printed Wiring Board – Panel Section – ............................. 17 3-8. Schematic Diagram – Power Section – ............................... 19 3-9. Printed Wiring Board – Power Section – ............................ 21 3-10. IC Block Diagrams ............................................................ 23 3-11. IC Pin Function ................................................................. 24 4. EXPLODED VIEW 4-1. Case and Back Panel Section .............................................. 25 4-2. Front Panel Section ............................................................. 26 4-3. Chassis Section ................................................................... 27 5. ELECTRICAL PARTS LIST ........................................ 28 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 3 – Front Panel Descriptions SECTION 1 GENERAL 1 PROTECTION indicator 2 U (Power) button 3 Remote sensor 4 TAPE 1/DAT indicator 5 TAPE 2/MD indicator 6 AUX indicator 7 CD indicator 8 TUNER indicator 9 PHONO indicator 10 INPUT SELECTOR knob 11 VOLUME knob 12 SUBSONIC button 13 SOURCE DIRECT button and indicator 14 LOUDNESS button 15 TAPE MONITOR knob 16 BALANCE knob 17 TREBLE knob 18 BASS knob 19 SPEAKERS knob 20 PHONE jack 21 EON LINK button This section is extracted from instruction manual. 10 3 2 1 9 7 8 4 6 5 11 13 12 14 15 16 17 18 19 20 21 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 4 – SECTION 2 ELECTRICAL ADJUSTMENT Bias Adjustment NOTE: 1. Perform the adjustment after the unit has warmed up sufficiently. 2. Perform the bias adjustment if the power transistor has been replaced. Procedure: 1. Rotate fully the bias adjusting semi-fixed resistors (RV500, RV600) to the MIN position (counterclockwise). 2. Connect a digital voltmeter to the CN500 and CN600. 3. Set the slide regulator to 0V, and press the U button (ON) on the set. 4. Raise gradually the slide regulator voltage up to the rated voltage. 5. At this time, confirm that the SP relay is turned on (it will click). 6. Adjust the RV500 and RV600 so that a reading of digital voltmeter is 10 ± 0.1 mV. 7. Return the slidack to 0 V, and press the U button (OFF) on the set. Adjustment Location : [MAIN BOARD] – COMPONENT SIDE – 1 pin 3 pin – – + + CN500 (L-CH) CN600(R-CH) + CN600 (R-CH) 1 3 CN500 (L-CH) 1 3 RV600 Bias (R-CH) RV500 Bias (L-CH) DIGITAL VOLTMETER DIGITAL VOLTMETER + www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 5 – – 6 – SECTION 3 DIAGRAMS 3-1. CIRCUIT BOARDS LOCATION THIS NOTE IS COMMON FOR PRINTED WIRING BOARDS AND SCHEMATIC DIAGRAMS. (In addition to this, the necessary note is printed in each block.) For schematic diagrams. Note: • All capacitors are in µF unless otherwise noted. pF: µµF 50 WV or less are not indicated except for electrolytics and tantalums. • All resistors are in Ω and 1/4 W or less unless otherwise specified. • ¢ : internal component. • 2 : nonflammable resistor. • 5 : fusible resistor. • C : panel designation. For printed wiring boards. Note: • X : parts extracted from the component side. • Y : parts extracted from the conductor side. • b : Pattern from the side which enables seeing. • U : B+ Line. • V : B– Line. • H : adjustment for repair. • Voltages and waveforms are dc with respect to ground under no-signal (detuned) conditions. no mark : POWER ON • Voltages are taken with a VOM (Input impedance 10 MΩ). Voltage variations may be noted due to normal produc- tion tolerances. • Waveforms are taken with a oscilloscope. Voltage variations may be noted due to normal produc- tion tolerances. • Circled numbers refer to waveforms. • Signal path. F : TUNER WAVEFORM 1 IC902 1 XOUT Note: The components identified by mark ! or dotted line with mark ! are critical for safety. Replace only with part number specified. • Indication of transistor C These are omitted E B 4MHz 3.8Vp-p PANEL board INPUT board MAIN board SP-TM board PHONO board PS board OUTLET board VOL board SIRCS board SIRCS SUB board HP board SP-SW board w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 7 – – 8 – TA-FB720R/FB820R 3-2. SCHEMATIC DIAGRAM – INPUT SECTION – • See page 23 for IC Block Diagrams. (Page 15) (Page 15) (Page 12) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 9 – – 10 – TA-FB720R/FB820R 3-3. PRINTED WIRING BOARD – INPUT SECTION – • See page 5 for Circuit Boards Location. Ref. No. Location • Semiconductor Location D101 B-7 D102 B-8 D133 C-9 D140 B-4 D240 B-4 IC101 B-9 Q101 C-7 Q102 C-7 Q103 C-8 Q140 C-4 Q240 B-4 (Page 18) (Page 17) (Page 13) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 11 – – 12 – TA-FB720R/FB820R 3-4. SCHEMATIC DIAGRAM – MAIN SECTION – • See page 23 for IC Block Diagrams. (Page 16) (Page 16) (Page 20) (Page 15) (Page 8) (Page 20) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 13 – – 14 – TA-FB720R/FB820R 3-5. PRINTED WIRING BOARD – MAIN SECTION – • See page 5 for Circuit Boards Location. Ref. No. Location • Semiconductor Location D500 C-10 D501 C-10 D502 C-10 D503 E-11 D504 E-10 D505 E-10 D506 D-9 D511 E-2 D512 E-2 D513 F-3 D600 G-10 D601 G-10 D602 G-10 D603 E-11 D604 E-10 D605 E-10 D606 F-9 D700 A-1 D701 A-1 D702 A-1 D703 G-4 D720 E-7 D721 E-7 IC700 B-2 Q500 C-11 Q501 C-11 Q502 C-10 Q503 D-11 Q504 D-10 Q505 D-10 Q506 E-11 Q507 E-10 Q508 D-9 Q509 D-8 Q510 D-8 Q511 C-5 Q512 C-8 Q513 D-6 Q600 G-11 Q601 G-11 Q602 G-10 Q603 F-11 Q604 F-10 Q605 F-10 Q606 E-11 Q607 E-10 Q608 F-9 Q609 F-8 Q610 F-10 Q611 G-8 Q612 G-5 Q613 F-6 Q700 B-3 Q701 B-1 Q702 G-4 (Page 22) (Page 10) (Page 22) (Page 18) (Page 18) (Page 17) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 15 – – 16 – TA-FB720R/FB820R 3-6. SCHEMATIC DIAGRAM – PANEL SECTION – • See page 5 for Waveforms. • See page 23 for IC Block Diagram. • See page 24 for IC Pin Function. (Page 8) (Page 12) (Page 7) (Page 11) (Page 11) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 17 – – 18 – TA-FB720R/FB820R 3-7. PRINTED WIRING BOARD – PANEL SECTION – • See page 5 for Circuit Boards Location. Ref. No. Location • Semiconductor Location (Page 14) (Page 9) (Page 18) (Page 14) D902 D-9 D903 D-9 D904 E-8 D905 D-7 D906 D-7 D907 C-7 D908 B-10 D910 C-1 D912 C-6 D913 C-1 D914 D-1 D915 D-1 D916 E-6 D917 D-4 D918 C-3 D919 D-4 D920 C-3 D921 D-5 D922 D-5 D923 D-3 D924 D-3 IC901 D-7 IC902 D-5 Q900 C-1 Q901 D-1 Q902 D-1 Q903 D-1 Q905 D-1 Q906 D-1 Q907 C-3 Q908 C-4 Q909 D-2 Q910 C-6 Q911 D-3 Q912 D-6 Q913 D-3 Q914 D-3 Q915 D-4 (Page 14) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 19 – – 20 – TA-FB720R/FB820R 3-8. SCHEMATIC DIAGRAM – POWER SECTION – (Page 12) (Page 11) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 21 – – 22 – TA-FB720R/FB820R 3-9. PRINTED WIRING BOARD – POWER SECTION – • See page 5 for Circuit Boards Location. (Page 14) (Page 13) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 23 – – 24 – 3-11. IC PIN FUNCTION • IC902 Input Control & LED Drive (TMP47C103N-JP47) O I I I O O I I I I O O O — O O O O O I I I O O O O I — 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 X OUT X IN RESET PMD VOL + VOL – SW 0 SW 1 SW 2 EON PHONO TUNER CD GND AUX MD/DAT TAPE MON PRY PKY MOI SIRCS MUTE SCE SDT SCK STOP +3V System clock (4MHz) Reset input Mode select input Motor drive output (+) Motor drive output (–) Rotary switch input (CD) Rotary switch input (TUNER) Rotary switch input (PHONO) EON signal input PHONO LED drive output TUNER LED drive output CD LED drive output Ground AUX LED drive output TAPE “2” LED drive output TAPE “1” LED drive output MONITOR output Power relay output Power key input MONITOR input SIRCS input Muting output Chip enble output Serial data output Serial clock output STOP input +3V Power supply I/O Function Pin No. Pin Name 3-10. IC BLOCK DIAGRAMS • Main section IC700 uPC1237HA 1 2 3 4 5 6 7 8 OVER LOAD DET F/F OFFSET DET LATCH/ AUTORESET VCC ON MUTE AC OFF DET VCC • Panel section IC901 BA6208 1 2 3 4 5 6 7 8 9 NC OUTPUT 2 Vcc GND NC INPUT 2 INPUT 1 NC MOTOR DRIVE MOTOR DRIVE REG SWITCH SWITCH OUTPUT1 • Input section IC101 LC7821 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 CONTROL LATCH SHIFT RESISTER LEVEL SHIFT CL DI CE VEE L COM3 L7 L COM2 L5 L4 L2 VSS S RES VDD R COM3 R8 R7 R COM2 R6 R4 R2 R5 R COM1 R3 R1 L3 L1 L COM1 L6 L8 BUFFER w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 25 – SECTION 4 EXPLODED VIEW NOTE: • Items marked “*” are not stocked since they are seldom required for routine service. Some delay should be anticipated when ordering these items. • The mechanical parts with no reference number in the exploded views are not supplied. • Hardware (# mark) list and accessories and packing materials are given in the last of this parts list. Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark The components identified by mark ! or dotted line with mark ! are critical for safety. Replace only with part number specified. 4-1. CASE AND BACK PANEL SECTION * 10 3-703-244-00 BUSHING (2104), CORD !11 1-777-185-11 CORD, POWER * 12 1-669-476-11 OUTLET BOARD 13 3-710-901-11 SCREW, TAPPING 14 4-947-010-01 SCREW, FEEDER FIXED 15 3-704-515-41 SCREW (BV/RING) !CNJ3 1-526-794-11 OUTLET, AC !CNJ4 1-526-794-11 OUTLET, AC 1 X-4949-780-1 KNOB (SELECTOR) ASSY 2 X-4949-781-1 KNOB (VOLUME) ASSY * 4 4-999-439-01 CASE (413235) 5 X-4949-760-1 FOOT ASSY 6 4-970-124-01 CUSHION (F50180S) * 7 A-4407-621-A PHONO BOARD, COMPLETE (FB720R) * 7 A-4407-640-A PHONO BOARD, COMPLETE (FB820R) 8 4-967-961-01 SCREW (3X8) * 9 4-999-451-11 PANEL, BACK (FB820R) * 9 4-999-451-21 PANEL, BACK (FB720R) 13 13 12 11 10 9 CNJ3 CNJ4 15 14 15 15 8 4 13 13 7 8 6 5 #2 not supplied not supplied #2 5 6 1 2 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 26 – 4-2. FRONT PANEL SECTION Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark * 62 1-670-220-11 SIRCS SUB BOARD * 63 1-669-497-11 SIRCS BOARD * 65 1-669-494-11 SP-SW BOARD * 66 A-4407-623-A PANEL BOARD, COMPLETE (FB720R) * 66 A-4407-632-A PANEL BOARD, COMPLETE (FB820R) * 67 1-669-496-11 VOL BOARD 68 4-950-189-01 KNOB (A) (VOL) 69 4-970-146-01 BUTTON 70 4-980-189-01 KNOB (DIA. 6) 71 4-999-420-01 ESCUTCHEON (TONE) * 72 1-669-498-11 HP BOARD !S1 1-554-920-61 SWITCH, PUSH (AC POWER)(1 KEY)(U) 51 4-942-568-41 EMBLEM (NO.5), SONY 52 4-965-651-01 EMBLEM (MOS) 53 4-967-961-01 SCREW (3X8) 54 4-999-415-01 PANEL, FRONT (FB820R) 54 4-999-415-11 PANEL, FRONT (FB720R) 55 4-999-413-01 INDICATOR (PROTECTION) 56 4-980-776-01 WINDOW, REMOTE CONTROL * 57 4-999-418-01 INDICATOR (SELECTOR) 58 4-999-416-01 BASE (L), PANEL 59 4-999-417-01 BASE (R), PANEL 60 4-999-419-01 KNOB (D23) 61 3-024-055-01 BUTTON (POWER) The components identified by mark ! or dotted line with mark ! are critical for safety. Replace only with part number specified. 51 52 53 53 53 53 54 55 57 71 55 68 53 53 53 60 61 53 72 53 53 69 70 67 53 53 S1 not supplied not supplied Supplied with J801 Supplied with RV300, S902,S903 Supplied with RV301,RV302, RV303,S801 53 63 62 66 65 58 59 53 56 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 27 – 4-3. CHASSIS SECTION Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark * 107 1-669-473-11 PS BOARD Q511 8-729-232-45 TRANSISTOR 2SK1529-Y Q512 8-729-232-46 TRANSISTOR 2SJ200-Y Q611 8-729-232-45 TRANSISTOR 2SK1529-Y Q612 8-729-232-46 TRANSISTOR 2SJ200-Y Q702 8-729-209-15 TRANSISTOR 2SD2012 !T1 1-431-870-11 TRANSFORMER, POWER (FB720R) !T1 1-431-872-11 TRANSFORMER, POWER (FB820R) 101 4-967-961-01 SCREW (3X8) 102 3-905-609-11 SCREW (TRANSISTOR) 103 4-967-960-01 SCREW (4X8) * 104 A-4407-624-A INPUT BOARD, COMPLETE (FB720R) * 104 A-4407-636-A INPUT BOARD, COMPLETE (FB820R) * 105 A-4407-618-A MAIN BOARD, COMPLETE (FB720R) * 105 A-4407-637-A MAIN BOARD, COMPLETE (FB820R) * 106 A-4407-619-A SP-TM BOARD, COMPLETE (FB720R) * 106 A-4407-638-A SP-TM BOARD, COMPLETE (FB820R) The components identified by mark ! or dotted line with mark ! are critical for safety. Replace only with part number specified. not supplied not supplied not supplied not supplied not supplied not supplied not supplied Q511 Q611 Q612 Q702 Q512 T1 not supplied 101 101 101 101 101 104 101 101 101 101 101 101 101 101 101 101 103 103 107 102 105 102 106 101 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 28 – • SEMICONDUCTORS In each case, u: µ , for example: uA...: µ A..., uPA...: µ PA..., uPB...: µ PB..., uPC...: µ PC..., uPD...: µ PD... • CAPACITORS uF : µ F • COILS uH : µ H • Due to standardization, replacements in the parts list may be different from the parts specified in the diagrams or the components used on the set. • -XX, -X mean standardized parts, so they may have some difference from the original one. • Items marked “*” are not stocked since they are seldom required for routine service. Some delay should be anticipated when ordering these items. • RESISTORS All resistors are in ohms METAL: Metal-film resistor METAL OXIDE: Metal Oxide-film resistor F : nonflammable SECTION 5 ELECTRICAL PARTS LIST Note: When indicating parts by reference number, please include the board name. Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark The components identified by mark ! or dotted line with mark ! are critical for safety. Replace only with part number specified. HP * 1-669-498-11 HP BOARD ******** < CONNECTOR > CN804 1-691-765-11 PLUG (MICRO CONNECTOR) 3P < JACK > J801 1-770-307-11 JACK (LARGE TYPE)(PHONES) ************************************************************** * A-4407-624-A INPUT BOARD, COMPLETE (FB720R) ********************* * A-4407-636-A INPUT BOARD, COMPLETE (FB820R) ********************* < CAPACITOR > C101 1-162-282-31 CERAMIC 100PF 10% 50V C102 1-162-282-31 CERAMIC 100PF 10% 50V C103 1-162-282-31 CERAMIC 100PF 10% 50V C104 1-162-282-31 CERAMIC 100PF 10% 50V C105 1-162-282-31 CERAMIC 100PF 10% 50V C131 1-164-159-11 CERAMIC 0.1uF 50V C132 1-164-159-11 CERAMIC 0.1uF 50V (FB820R) C133 1-162-294-31 CERAMIC 0.001uF 10% 50V C134 1-164-159-11 CERAMIC 0.1uF 50V C135 1-164-159-11 CERAMIC 0.1uF 50V C140 1-126-052-11 ELECT 100uF 20% 50V C141 1-126-023-11 ELECT 100uF 20% 25V C142 1-126-013-11 ELECT 1000uF 20% 16V C201 1-162-282-31 CERAMIC 100PF 10% 50V C202 1-162-282-31 CERAMIC 100PF 10% 50V C203 1-162-282-31 CERAMIC 100PF 10% 50V C204 1-162-282-31 CERAMIC 100PF 10% 50V C205 1-162-282-31 CERAMIC 100PF 10% 50V C240 1-126-052-11 ELECT 100uF 20% 50V C241 1-126-023-11 ELECT 100uF 20% 25V C242 1-126-013-11 ELECT 1000uF 20% 16V < CONNECTOR > CN102 1-691-768-11 PLUG (MICRO CONNECTOR) 6P CN103 1-691-771-11 PLUG (MICRO CONNECTOR) 9P CN104 1-691-765-11 PLUG (MICRO CONNECTOR) 3P < DIODE > D101 8-719-911-19 DIODE 1SS119-25 D102 8-719-911-19 DIODE 1SS119-25 (FB820R) D133 8-719-911-19 DIODE 1SS119-25 D140 8-719-986-38 DIODE HZS16-1LTA D240 8-719-986-38 DIODE HZS16-1LTA < IC > IC101 8-759-805-13 IC LC7821 < JACK > J101 1-774-411-11 JACK, PIN 6P (TUNER, CD, AUX IN) J102 1-573-028-31 JACK, PIN 4P (TAPE2/MD) J103 1-573-028-31 JACK, PIN 4P (TAPE1/DAT) < TRANSISTOR > Q101 8-729-620-05 TRANSISTOR 2SC2603-EF Q102 8-729-620-05 TRANSISTOR 2SC2603-EF Q103 8-729-620-05 TRANSISTOR 2SC2603-EF Q140 8-729-119-78 TRANSISTOR 2SC2785-HFE Q240 8-729-201-53 TRANSISTOR 2SA1015-GR < RESISTOR > R101 1-259-239-11 CARBON 1M 5% 1/4W (FB820R) R101 1-259-500-91 CARBON 1M 5% 1/6W (FB720R) R102 1-259-239-11 CARBON 1M 5% 1/4W (FB820R) R102 1-259-500-91 CARBON 1M 5% 1/6W (FB720R) R103 1-259-239-11 CARBON 1M 5% 1/4W (FB820R) R103 1-259-500-91 CARBON 1M 5% 1/6W (FB720R) R104 1-259-239-11 CARBON 1M 5% 1/4W (FB820R) R104 1-259-500-91 CARBON 1M 5% 1/6W (FB720R) R105 1-259-239-11 CARBON 1M 5% 1/4W (FB820R) R105 1-259-500-91 CARBON 1M 5% 1/6W (FB720R) R114 1-259-239-11 CARBON 1M 5% 1/4W (FB820R) R114 1-259-500-91 CARBON 1M 5% 1/6W (FB720R) R115 1-259-239-11 CARBON 1M 5% 1/4W (FB820R) R115 1-259-500-91 CARBON 1M 5% 1/6W (FB720R) R124 1-259-167-21 CARBON 1K 5% 1/4W (FB820R) INPUT www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 29 – Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark MAIN R124 1-259-428-11 CARBON 1K 5% 1/6W (FB720R) R125 1-259-167-21 CARBON 1K 5% 1/4W (FB820R) R125 1-259-428-11 CARBON 1K 5% 1/6W (FB720R) R130 1-249-425-11 CARBON 4.7K 5% 1/4W F R131 1-249-429-11 CARBON 10K 5% 1/4W R132 1-249-429-11 CARBON 10K 5% 1/4W R133 1-249-429-11 CARBON 10K 5% 1/4W R140 1-249-198-11 CARBON 330 5% 1/3W R141 1-249-198-11 CARBON 330 5% 1/3W R142 1-249-198-11 CARBON 330 5% 1/3W R143 1-249-198-11 CARBON 330 5% 1/3W R144 1-259-187-11 CARBON 6.8K 5% 1/4W R201 1-259-500-91 CARBON 1M 5% 1/6W (FB720R) R201 1-259-239-11 CARBON 1M 5% 1/4W (FB820R) R202 1-259-500-91 CARBON 1M 5% 1/6W (FB720R) R202 1-259-239-11 CARBON 1M 5% 1/4W (FB820R) R203 1-259-500-91 CARBON 1M 5% 1/6W (FB720R) R203 1-259-239-11 CARBON 1M 5% 1/4W (FB820R) R204 1-259-500-91 CARBON 1M 5% 1/6W (FB720R) R204 1-259-239-11 CARBON 1M 5% 1/4W (FB820R) R205 1-259-500-91 CARBON 1M 5% 1/6W (FB720R) R205 1-259-239-11 CARBON 1M 5% 1/4W (FB820R) R214 1-259-500-91 CARBON 1M 5% 1/6W (FB720R) R214 1-259-239-11 CARBON 1M 5% 1/4W (FB820R) R215 1-259-500-91 CARBON 1M 5% 1/6W (FB720R) R215 1-259-239-11 CARBON 1M 5% 1/4W (FB820R) R224 1-259-428-11 CARBON 1K 5% 1/6W (FB720R) R224 1-259-167-21 CARBON 1K 5% 1/4W (FB820R) R225 1-259-428-11 CARBON 1K 5% 1/6W (FB720R) R225 1-259-167-21 CARBON 1K 5% 1/4W (FB820R) R240 1-249-198-11 CARBON 330 5% 1/3W R241 1-249-198-11 CARBON 330 5% 1/3W R242 1-249-198-11 CARBON 330 5% 1/3W R243 1-249-198-11 CARBON 330 5% 1/3W R244 1-259-187-11 CARBON 6.8K 5% 1/4W < RELAY > RY101 1-515-614-11 RELAY RY102 1-515-614-11 RELAY (FB820R) ************************************************************** * A-4407-618-A MAIN BOARD, COMPLETE (FB720R) ******************** * A-4407-637-A MAIN BOARD, COMPLETE (FB820R) ******************** < CAPACITOR > C500 1-102-973-00 CERAMIC 100PF 5% 50V C501 1-124-721-11 ELECT 10uF 20% 50V C502 1-101-880-00 CERAMIC 47PF 5% 50V C503 1-102-820-00 CERAMIC 330PF 5% 50V C504 1-126-023-11 ELECT 100uF 20% 16V C505 1-107-587-11 CERAMIC 7PF 0.5PF 500V C506 1-126-023-11 ELECT 100uF 20% 16V C507 1-126-023-11 ELECT 100uF 20% 16V C508 1-126-023-11 ELECT 100uF 20% 16V C509 1-102-937-00 CERAMIC 4.0PF ±0.25PF 50V C510 1-126-365-51 ELECT 100uF 20% 63V C511 1-102-978-00 CERAMIC 220PF 5% 50V C512 1-136-163-00 FILM 0.068uF 5% 50V C513 1-136-163-00 FILM 0.068uF 5% 50V C517 1-126-023-11 ELECT 100uF 20% 16V C600 1-102-973-00 CERAMIC 100PF 5% 50V C601 1-124-721-11 ELECT 10uF 20% 50V C602 1-101-880-00 CERAMIC 47PF 5% 50V C603 1-102-820-00 CERAMIC 330PF 5% 50V C604 1-126-023-11 ELECT 100uF 20% 16V C605 1-107-587-11 CERAMIC 7PF 0.5PF 500V C606 1-126-023-11 ELECT 100uF 20% 16V C607 1-126-023-11 ELECT 100uF 20% 16V C608 1-126-023-11 ELECT 100uF 20% 16V C609 1-102-937-00 CERAMIC 4.0PF ±0.25PF 50V C610 1-126-365-51 ELECT 100uF 20% 63V C611 1-102-978-00 CERAMIC 220PF 5% 50V C612 1-136-163-00 FILM 0.068uF 5% 50V C613 1-136-163-00 FILM 0.068uF 5% 50V C617 1-126-023-11 ELECT 100uF 20% 16V C712 1-126-967-11 ELECT 47uF 20% 50V C713 1-126-933-11 ELECT 100uF 20% 16V C714 1-126-964-11 ELECT 10uF 20% 50V C720 1-126-056-11 ELECT 1000uF 20% 50V (FB720R) C720 1-126-170-11 ELECT 1000uF 20% 50V (FB820R) C721 1-126-056-11 ELECT 1000uF 20% 50V (FB720R) C721 1-126-170-11 ELECT 1000uF 20% 50V (FB820R) < CONNECTOR > CN500 1-564-506-11 PLUG, CONNECTOR 3P CN503 1-691-770-11 PLUG (MICRO CONNECTOR) 8P CN600 1-564-506-11 PLUG, CONNECTOR 3P CN700 1-691-768-11 PLUG (MICRO CONNECTOR) 6P < DIODE > D500 8-719-911-19 DIODE 1SS119-25 D501 8-719-911-19 DIODE 1SS119-25 INPUT www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 30 – Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark D502 8-719-911-19 DIODE 1SS119-25 D503 8-719-933-39 DIODE HZS6C1L D504 8-719-911-19 DIODE 1SS119-25 D505 8-719-911-19 DIODE 1SS119-25 D506 8-719-310-61 DIODE SEL1510C-D D600 8-719-911-19 DIODE 1SS119-25 D601 8-719-911-19 DIODE 1SS119-25 D602 8-719-911-19 DIODE 1SS119-25 D603 8-719-933-39 DIODE HZS6C1L D604 8-719-911-19 DIODE 1SS119-25 D605 8-719-911-19 DIODE 1SS119-25 D606 8-719-310-61 DIODE SEL1510C-D D703 8-719-933-39 DIODE HZS6C1L D720 8-719-024-99 DIODE 11ES2-NTA2B D721 8-719-024-99 DIODE 11ES2-NTA2B < BRIDGE > JWH711 4-999-918-01 BRIDGE (PC-BOARD) JWH712 4-999-918-01 BRIDGE (PC-BOARD) JWH713 4-999-918-01 BRIDGE (PC-BOARD) JWH714 4-999-918-01 BRIDGE (PC-BOARD) JWH715 4-999-918-01 BRIDGE (PC-BOARD) < TRANSISTOR > Q500 8-729-045-15 TRANSISTOR 2SC5169-FG Q501 8-729-201-53 TRANSISTOR 2SA1015-GR Q502 8-729-201-53 TRANSISTOR 2SA1015-GR Q503 8-729-201-53 TRANSISTOR 2SA1015-GR Q504 8-729-021-74 TRANSISTOR 2SA949-OY-TPE6 Q505 8-729-202-67 TRANSISTOR 2SK246-GR3 Q506 8-729-119-78 TRANSISTOR 2SC2785-HFE Q507 8-729-021-73 TRANSISTOR 2SC2229-OY-TPE6 Q508 8-729-119-78 TRANSISTOR 2SC2785-HFE Q509 8-729-104-18 TRANSISTOR 2SC3514 Q510 8-729-104-91 TRANSISTOR 2SA1383 Q511 8-729-232-45 TRANSISTOR 2SK1529-Y Q512 8-729-232-46 TRANSISTOR 2SJ200-Y Q513 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA Q600 8-729-045-15 TRANSISTOR 2SC5169-FG Q601 8-729-201-53 TRANSISTOR 2SA1015-GR Q602 8-729-201-53 TRANSISTOR 2SA1015-GR Q603 8-729-201-53 TRANSISTOR 2SA1015-GR Q604 8-729-021-74 TRANSISTOR 2SA949-OY-TPE6 Q605 8-729-202-67 TRANSISTOR 2SK246-GR3 Q606 8-729-119-78 TRANSISTOR 2SC2785-HFE Q607 8-729-021-73 TRANSISTOR 2SC2229-OY-TPE6 Q608 8-729-119-78 TRANSISTOR 2SC2785-HFE Q609 8-729-104-18 TRANSISTOR 2SC3514 Q610 8-729-104-91 TRANSISTOR 2SA1383 Q611 8-729-232-45 TRANSISTOR 2SK1529-Y Q612 8-729-232-46 TRANSISTOR 2SJ200-Y Q613 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA Q702 8-729-209-15 TRANSISTOR 2SD2012 < RESISTOR > R500 1-259-167-21 CARBON 1K 5% 1/4W R501 1-259-215-21 CARBON 100K 5% 1/4W R502 1-259-151-21 CARBON 220 5% 1/4W R503 1-259-151-21 CARBON 220 5% 1/4W R504 1-259-151-21 CARBON 220 5% 1/4W R505 1-259-179-21 CARBON 3.3K 5% 1/4W R506 1-259-151-21 CARBON 220 5% 1/4W R507 1-259-151-21 CARBON 220 5% 1/4W R508 1-249-244-11 CARBON 27K 5% 1/3W R509 1-259-175-11 CARBON 2.2K 5% 1/4W R510 1-259-183-11 CARBON 4.7K 5% 1/4W !R511 1-249-899-11 CARBON 100 5% 1/4W F R512 1-259-171-21 CARBON 1.5K 5% 1/4W R513 1-259-167-21 CARBON 1K 5% 1/4W R514 1-249-258-11 CARBON 100K 5% 1/3W R515 1-259-143-21 CARBON 100 5% 1/4W R516 1-249-204-11 CARBON 560 5% 1/3W !R517 1-247-688-11 CARBON 10 5% 1/4W F !R518 1-247-688-11 CARBON 10 5% 1/4W F !R519 1-247-745-11 CARBON 330 5% 1/2W F !R520 1-249-899-11 CARBON 100 5% 1/4W F !R521 1-249-899-11 CARBON 100 5% 1/4W F !R522 1-208-601-11 REGISTER 0.1 10% 2W F !R523 1-208-601-11 REGISTER 0.1 10% 2W F R524 1-259-436-11 CARBON 2.2K 5% 1/6W R525 1-259-432-11 CARBON 1.5K 5% 1/6W R526 1-249-162-11 CARBON 10 5% 1/3W R527 1-259-484-11 CARBON 220K 5% 1/6W R600 1-259-167-21 CARBON 1K 5% 1/4W R601 1-259-215-21 CARBON 100K 5% 1/4W R602 1-259-151-21 CARBON 220 5% 1/4W R603 1-259-151-21 CARBON 220 5% 1/4W R604 1-259-151-21 CARBON 220 5% 1/4W R605 1-259-179-21 CARBON 3.3K 5% 1/4W R606 1-259-151-21 CARBON 220 5% 1/4W R607 1-259-151-21 CARBON 220 5% 1/4W R608 1-249-244-11 CARBON 27K 5% 1/3W R609 1-259-175-11 CARBON 2.2K 5% 1/4W R610 1-259-183-11 CARBON 4.7K 5% 1/4W !R611 1-249-899-11 CARBON 100 5% 1/4W F R612 1-259-171-21 CARBON 1.5K 5% 1/4W R613 1-259-167-21 CARBON 1K 5% 1/4W R614 1-249-258-11 CARBON 100K 5% 1/3W R615 1-259-143-21 CARBON 100 5% 1/4W R616 1-249-204-11 CARBON 560 5% 1/3W !R617 1-247-688-11 CARBON 10 5% 1/4W F !R618 1-247-688-11 CARBON 10 5% 1/4W F !R619 1-247-745-11 CARBON 330 5% 1/2W F !R620 1-249-899-11 CARBON 100 5% 1/4W F !R621 1-249-899-11 CARBON 100 5% 1/4W F !R622 1-208-601-11 REGISTER 0.1 10% 2W F !R623 1-208-601-11 REGISTER 0.1 10% 2W F R624 1-259-436-11 CARBON 2.2K 5% 1/6W R625 1-259-432-11 CARBON 1.5K 5% 1/6W R626 1-249-162-11 CARBON 10 5% 1/3W R627 1-259-484-11 CARBON 220K 5% 1/6W R709 1-249-425-11 CARBON 4.7K 5% 1/4W F MAIN The components identified by mark ! or dotted line with mark ! are critical for safety. Replace only with part number specified. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 31 – Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark PANEL < VARIABLE RESISTOR > RV500 1-241-762-11 RES, ADJ, CARBON 2.2K RV600 1-241-762-11 RES, ADJ, CARBON 2.2K ************************************************************** * 1-669-476-11 OUTLET BOARD ************ < CONNECTOR > !CNJ3 1-526-794-11 OUTLET, AC (AC OUTLET) !CNJ4 1-526-794-11 OUTLET, AC (AC OUTLET) < FUSE > !F2 1-532-464-51 FUSE, TIME LAG (T2.5AL 250V) < FUSE HOLDER > FH3 1-533-233-11 HOLDER, FUSE FH4 1-533-233-11 HOLDER, FUSE ************************************************************** * A-4407-623-A PANEL BOARD, COMPLETE (FB720R) ********************* * A-4407-632-A PANEL BOARD, COMPLETE (FB820R) ********************* < CAPACITOR > C300 1-136-171-00 FILM 0.33uF 5% 50V C301 1-130-475-00 MYLAR 0.0022uF 5% 50V C302 1-136-153-00 FILM 0.01uF 5% 50V C303 1-136-155-00 FILM 0.015uF 5% 50V C304 1-136-165-00 FILM 0.1uF 5% 50V C305 1-136-165-00 FILM 0.1uF 5% 50V C306 1-130-471-00 MYLAR 0.001uF 5% 50V C400 1-136-171-00 FILM 0.33uF 5% 50V C401 1-130-475-00 MYLAR 0.0022uF 5% 50V C402 1-136-153-00 FILM 0.01uF 5% 50V C403 1-136-155-00 FILM 0.015uF 5% 50V C404 1-136-165-00 FILM 0.1uF 5% 50V C405 1-136-165-00 FILM 0.1uF 5% 50V C406 1-130-471-00 MYLAR 0.001uF 5% 50V C900 1-126-786-11 ELECT 47uF 20% 16V C901 1-126-916-11 ELECT 1000uF 20% 6.3V C902 1-162-294-31 CERAMIC 0.001uF 10% 50V C903 1-162-294-31 CERAMIC 0.001uF 10% 50V C904 1-164-159-11 CERAMIC 0.1uF 50V C905 1-162-294-31 CERAMIC 0.001uF 10% 50V C906 1-126-795-11 ELECT 10uF 20% 50V C907 1-162-294-31 CERAMIC 0.001uF 10% 50V C908 1-126-786-11 ELECT 47uF 20% 16V C909 1-126-795-11 ELECT 10uF 20% 50V C910 1-126-794-11 ELECT 4.7uF 20% 50V C911 1-126-795-11 ELECT 10uF 20% 50V C912 1-126-786-11 ELECT 47uF 20% 16V < CONNECTOR > * CN300 1-564-522-11 PLUG, CONNECTOR 7P * CN301 1-564-526-11 PLUG, CONNECTOR 11P CN901 1-691-763-51 PIN, CONNECTOR 8P * CN904 1-564-525-11 PLUG, CONNECTOR 10P * CN905 1-564-522-11 PLUG, CONNECTOR 7P * CN906 1-564-520-11 PLUG, CONNECTOR 5P < DIODE > D902 8-719-313-50 DIODE SEL6810A-TH12 (PHONO) D903 8-719-313-50 DIODE SEL6810A-TH12 (TUNER) D904 8-719-313-50 DIODE SEL6810A-TH12 (CD) D905 8-719-313-50 DIODE SEL6810A-TH12 (AUX) D906 8-719-313-50 DIODE SEL6810A-TH12 (TAPE2/MD) D907 8-719-313-50 DIODE SEL6810A-TH12 (TAPE1/DAT) D908 8-719-313-50 DIODE SEL6810A-TH12 (SOURCE DIRECT) D910 8-719-911-19 DIODE 1SS119-25 D912 8-719-911-19 DIODE 1SS119-25 D913 8-719-911-19 DIODE 1SS119-25 D914 8-719-911-19 DIODE 1SS119-25 D915 8-719-911-19 DIODE 1SS119-25 D916 8-719-024-99 DIODE 11ES2-NTA2B D917 8-719-911-19 DIODE 1SS119-25 D918 8-719-985-66 DIODE HZS5BLL-TA D919 8-719-911-19 DIODE 1SS119-25 D920 8-719-911-19 DIODE 1SS119-25 D921 8-719-911-19 DIODE 1SS119-25 D922 8-719-911-19 DIODE 1SS119-25 D923 8-719-911-19 DIODE 1SS119-25 D924 8-719-911-19 DIODE 1SS119-25 < IC > IC901 8-759-962-08 IC BA6208 IC902 8-759-392-41 IC TMP47C103N-JP47 < TRANSISTOR > Q900 8-729-620-05 TRANSISTOR 2SC2603-EF Q901 8-729-900-63 TRANSISTOR DTA124ES Q902 8-729-900-63 TRANSISTOR DTA124ES Q903 8-729-900-80 TRANSISTOR DTC114ES Q905 8-729-422-57 TRANSISTOR UN4111 Q906 8-729-900-80 TRANSISTOR DTC114ES Q907 8-729-119-78 TRANSISTOR 2SC2785-HFE Q908 8-729-620-05 TRANSISTOR 2SC2603-EF Q909 8-729-620-05 TRANSISTOR 2SC2603-EF Q910 8-729-422-57 TRANSISTOR UN4111 Q911 8-729-201-53 TRANSISTOR 2SA1015-GR Q912 8-729-422-57 TRANSISTOR UN4111 (FB820R) Q913 8-729-900-80 TRANSISTOR DTC114ES (FB820R) Q914 8-729-119-76 TRANSISTOR 2SA1175-HFE Q915 8-729-620-05 TRANSISTOR 2SC2603-EF < RESISTOR > R300 1-259-500-11 CARBON 1M 5% 1/6W R301 1-259-500-11 CARBON 1M 5% 1/6W R302 1-259-446-11 CARBON 5.6K 5% 1/6W MAIN OUTLET The components identified by mark ! or dotted line with mark ! are critical for safety. Replace only with part number specified. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 32 – Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark PHONO R303 1-259-436-11 CARBON 2.2K 5% 1/6W R304 1-259-500-11 CARBON 1M 5% 1/6W R305 1-259-464-11 CARBON 33K 5% 1/6W R306 1-259-456-11 CARBON 15K 5% 1/6W R307 1-259-446-11 CARBON 5.6K 5% 1/6W R308 1-259-456-11 CARBON 15K 5% 1/6W R309 1-259-500-11 CARBON 1M 5% 1/6W R310 1-259-464-11 CARBON 33K 5% 1/6W R311 1-259-446-11 CARBON 5.6K 5% 1/6W R391 1-249-421-11 CARBON 1K 5% 1/4W F R392 1-249-421-11 CARBON 1K 5% 1/4W F R393 1-249-421-11 CARBON 1K 5% 1/4W F R400 1-259-500-11 CARBON 1M 5% 1/6W R401 1-259-500-11 CARBON 1M 5% 1/6W R402 1-259-446-11 CARBON 5.6K 5% 1/6W R403 1-259-436-11 CARBON 2.2K 5% 1/6W R404 1-259-500-11 CARBON 1M 5% 1/6W R405 1-259-464-11 CARBON 33K 5% 1/6W R406 1-259-456-11 CARBON 15K 5% 1/6W R407 1-259-446-11 CARBON 5.6K 5% 1/6W R408 1-259-456-11 CARBON 15K 5% 1/6W R409 1-259-500-11 CARBON 1M 5% 1/6W R410 1-259-464-11 CARBON 33K 5% 1/6W R411 1-259-446-11 CARBON 5.6K 5% 1/6W R902 1-247-239-00 CARBON 910 5% 1/2W R905 1-249-429-11 CARBON 10K 5% 1/4W R906 1-249-429-11 CARBON 10K 5% 1/4W R907 1-249-429-11 CARBON 10K 5% 1/4W R908 1-249-437-11 CARBON 47K 5% 1/4W R909 1-249-429-11 CARBON 10K 5% 1/4W R910 1-249-401-11 CARBON 47 5% 1/4W F R911 1-249-411-11 CARBON 330 5% 1/4W R912 1-249-429-11 CARBON 10K 5% 1/4W R913 1-249-425-11 CARBON 4.7K 5% 1/4W F R914 1-247-807-31 CARBON 100 5% 1/4W R917 1-249-433-11 CARBON 22K 5% 1/4W R918 1-249-421-11 CARBON 2.2K 5% 1/4W F R919 1-249-421-11 CARBON 2.2K 5% 1/4W F R920 1-249-429-11 CARBON 10K 5% 1/4W R921 1-249-429-11 CARBON 10K 5% 1/4W R922 1-249-429-11 CARBON 10K 5% 1/4W R923 1-249-429-11 CARBON 10K 5% 1/4W R924 1-249-429-11 CARBON 10K 5% 1/4W R925 1-249-406-11 CARBON 120 5% 1/4W F R927 1-249-403-11 CARBON 68 5% 1/4W F R929 1-247-903-00 CARBON 1M 5% 1/4W R930 1-247-807-31 CARBON 100 5% 1/4W R931 1-249-419-11 CARBON 1.5K 5% 1/4W F R932 1-249-427-11 CARBON 6.8K 5% 1/4W F R933 1-247-239-00 CARBON 910 5% 1/2W (FB720R) R934 1-247-843-11 CARBON 3.3K 5% 1/4W R935 1-247-843-11 CARBON 3.3K 5% 1/4W R936 1-249-429-11 CARBON 10K 5% 1/4W R937 1-249-429-11 CARBON 10K 5% 1/4W R938 1-249-429-11 CARBON 10K 5% 1/4W R939 1-247-751-11 CARBON 820 5% 1/2W (FB720R) R939 1-247-752-11 CARBON 1K 5% 1/2W (FB820R) < VARIABLE RESISTOR > RV301 1-223-789-11 RES, VAR, CARBON 250K/250K (BALANCE) RV302 1-223-768-11 RES, VAR, CARBON 250K/250K (TONE TREBLE) RV303 1-223-767-11 RES, VAR, CARBON 900K/900K (TONE BASS) < SWITCH > S301 1-762-203-11 SWITCH, PUSH (1 KEY)(SUBSONIC) S302 1-762-393-11 SWITCH, PUSH (SOURCE DIRECT) S303 1-762-387-11 SWITCH, PUSH (LOUDNESS) S902 1-692-974-11 SWITCH, ROTARY (INPUT SELECTOR) S903 1-771-386-11 SWITCH, ROTARY (TAPE MONITOR) < VIBRATOR > X900 1-577-358-21 VIBRATOR, CERAMIC (4.0MHz) ************************************************************** * A-4407-621-A PHONO BOARD, COMPLETE (FB720R) ********************* * A-4407-640-A PHONO BOARD, COMPLETE (FB820R) ********************* < CAPACITOR > C150 1-102-978-00 CERAMIC 220PF 5% 50V C151 1-126-048-11 ELECT 10uF 20% 50V C152 1-101-880-00 CERAMIC 47PF 5% 50V C153 1-106-359-00 MYLAR 4700PF 5% 200V C154 1-126-023-11 ELECT 100uF 20% 25V C155 1-136-162-00 FILM 0.056uF 5% 50V C156 1-137-471-11 FILM 0.016uF 5% 50V C157 1-126-048-11 ELECT 10uF 20% 50V C170 1-126-023-11 ELECT 100uF 20% 25V C171 1-136-165-00 FILM 0.1uF 5% 50V C172 1-136-165-00 FILM 0.1uF 5% 50V C250 1-102-978-00 CERAMIC 220PF 5% 50V C251 1-126-048-11 ELECT 10uF 20% 50V C252 1-101-880-00 CERAMIC 47PF 5% 50V C253 1-106-359-00 MYLAR 4700PF 5% 200V C254 1-126-023-11 ELECT 100uF 20% 25V C255 1-136-162-00 FILM 0.056uF 5% 50V C256 1-137-471-11 FILM 0.016uF 5% 50V C257 1-126-048-11 ELECT 10uF 20% 50V < CONNECTOR > CN151 1-691-768-11 PLUG (MICRO CONNECTOR) 6P < DIODE > D170 8-719-985-97 DIODE HZS7B1LTA < IC > IC150 8-759-636-74 IC M5218AP-22 (FB720R) IC150 8-759-701-25 IC NJM2068D-D (FB820R) PANEL www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 33 – Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark SIRCS < JACK > J150 1-764-593-21 JACK 2P (PHONO IN) < COIL > L150 1-410-977-11 INDUCTOR 100uH L151 1-410-977-11 INDUCTOR 100uH L250 1-410-977-11 INDUCTOR 100uH L251 1-410-977-11 INDUCTOR 100uH < TRANSISTOR > Q150 8-729-354-52 TRANSISTOR 2SC2545 Q151 8-729-354-52 TRANSISTOR 2SC2545 Q250 8-729-354-52 TRANSISTOR 2SC2545 Q251 8-729-354-52 TRANSISTOR 2SC2545 < RESISTOR > R150 1-259-175-11 CARBON 2.2K 5% 1/4W R151 1-249-911-11 CARBON 330 5% 1/4W R152 1-259-215-21 CARBON 100K 5% 1/4W R153 1-259-215-21 CARBON 100K 5% 1/4W R154 1-259-161-21 CARBON 560 5% 1/4W R155 1-259-161-21 CARBON 560 5% 1/4W R156 1-259-143-21 CARBON 100 5% 1/4W R157 1-259-191-21 CARBON 10K 5% 1/4W R158 1-259-144-11 CARBON 110 5% 1/4W R159 1-259-209-11 CARBON 56K 1% 1/4W (FB720R) R159 1-259-346-81 CARBON 56K 1% 1/2W (FB820R) R160 1-259-183-11 CARBON 4.7K 1% 1/4W (FB720R) R160 1-259-320-11 CARBON 4.7K 1% 1/2W (FB820R) R161 1-259-239-11 CARBON 1M 5% 1/4W R162 1-259-167-21 CARBON 1K 5% 1/4W R170 1-259-171-21 CARBON 1.5K 5% 1/4W R250 1-259-175-11 CARBON 2.2K 5% 1/4W R251 1-249-911-11 CARBON 330 5% 1/4W R252 1-259-215-21 CARBON 100K 5% 1/4W R253 1-259-215-21 CARBON 100K 5% 1/4W R254 1-259-161-21 CARBON 560 5% 1/4W R255 1-259-161-21 CARBON 560 5% 1/4W R256 1-259-143-21 CARBON 100 5% 1/4W R257 1-259-191-21 CARBON 10K 5% 1/4W R258 1-259-144-11 CARBON 110 5% 1/4W R259 1-259-209-11 CARBON 56K 1% 1/4W (FB720R) R259 1-259-346-81 CARBON 56K 1% 1/2W (FB820R) R260 1-259-183-11 CARBON 4.7K 1% 1/4W (FB720R) R260 1-259-320-11 CARBON 4.7K 1% 1/2W (FB820R) R261 1-259-239-11 CARBON 1M 5% 1/4W R262 1-259-167-21 CARBON 1K 5% 1/4W ************************************************************** * 1-669-473-11 PS BOARD ******** < CAPACITOR > C750 1-125-819-11 ELECT 6800uF 50V (FB720R) C750 1-125-820-11 ELECT 8200uF 50V (FB820R) C751 1-125-819-11 ELECT 6800uF 50V (FB720R) C751 1-125-820-11 ELECT 8200uF 50V (FB820R) C754 1-137-398-11 FILM 0.068uF 5% 100V C755 1-137-398-11 FILM 0.068uF 5% 100V < CONNECTOR > CN1 1-774-108-11 PIN, CONNECTOR (PC BOARD) CN2 1-564-321-00 PIN, CONNECTOR 2P CN3 1-564-321-00 PIN, CONNECTOR 2P * CN4 1-564-321-21 PIN, CONNECTOR 2P * CN750 1-564-687-11 PIN, CONNECTOR 3P * CN751 1-766-920-11 PIN, CONNECTOR 4P CN752 1-770-832-11 CONNECTOR, BOARD TO BOARD 6P < DIODE > D750 8-719-302-38 DIODE RBV-602-01 < FUSE > !F1 1-532-388-51 FUSE, TIME LAG (T2.0AL 250V)(FB720R) !F1 1-532-465-51 FUSE, TIME LAG (T3.15AL 250V)(FB820R) < FUSE HOLDER > FH1 1-533-233-11 HOLDER, FUSE FH2 1-533-233-11 HOLDER, FUSE ************************************************************** * 1-669-497-11 SIRCS BOARD *********** < CONNECTOR > * CN911 1-560-666-00 PIN, CONNECTOR 3P < DIODE > D900 8-719-046-46 DIODE SEL5221S-TH8F (PROTECTION) D901 8-719-046-38 DIODE SEL5821A-TH8F (EON LINK) < RESISTOR > R900 1-249-409-11 CARBON 220 5% 1/4W F R901 1-249-403-11 CARBON 68 5% 1/4W F R904 1-249-429-11 CARBON 10K 5% 1/4W < SWITCH > S901 1-571-112-21 SWITCH, PUSH (1 KEY)(EON LINK) ************************************************************** The components identified by mark ! or dotted line with mark ! are critical for safety. Replace only with part number specified. PHONO PS www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 34 – Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark SP-SW * 1-670-220-11 SIRCS SUB BOARD *************** < CONNECTOR > * CN912 1-565-835-11 SOCKET, CONNECTOR 3P < IC > IC900 8-749-014-66 IC NJL64H400A ************************************************************** * 1-669-494-11 SP-SW BOARD *********** < RESISTOR > R801 1-247-751-11 CARBON 820 5% 1/2W R802 1-247-751-11 CARBON 820 5% 1/2W R803 1-247-751-11 CARBON 820 5% 1/2W R804 1-247-751-11 CARBON 820 5% 1/2W R805 1-247-751-11 CARBON 820 5% 1/2W R806 1-247-751-11 CARBON 820 5% 1/2W R807 1-247-231-00 CARBON 430 5% 1/2W (FB820R) R807 1-247-746-11 CARBON 390 5% 1/2W F (FB720R) R808 1-247-231-00 CARBON 430 5% 1/2W (FB820R) R808 1-247-746-11 CARBON 390 5% 1/2W F (FB720R) R809 1-247-231-00 CARBON 430 5% 1/2W (FB820R) R809 1-247-746-11 CARBON 390 5% 1/2W F (FB720R) R810 1-247-231-00 CARBON 430 5% 1/2W (FB820R) R810 1-247-746-11 CARBON 390 5% 1/2W F (FB720R) < SWITCH > S801 1-771-385-11 SWITCH, ROTARY (SPEAKERS) ************************************************************** * A-4407-619-A SP-TM BOARD, COMPLETE (FB720R) ********************* * A-4407-638-A SP-TM BOARD, COMPLETE (FB820R) ********************* < CAPACITOR > C515 1-101-880-00 CERAMIC 100P 5% 50V C516 1-101-880-00 CERAMIC 100P 5% 50V C615 1-101-880-00 CERAMIC 100P 5% 50V C616 1-101-880-00 CERAMIC 100P 5% 50V C700 1-126-965-11 ELECT 22uF 20% 50V C701 1-136-163-00 FILM 0.068uF 5% 50V C702 1-124-995-11 ELECT 220uF 20% 10V C703 1-136-157-00 FILM 0.022uF 5% 50V C704 1-126-967-11 ELECT 47uF 20% 16V C705 1-126-967-11 ELECT 47uF 20% 16V C706 1-137-150-11 MYLAR 0.01uF 10% 100V C707 1-137-150-11 MYLAR 0.01uF 10% 100V C708 1-128-578-11 ELECT 1uF 20% 100V C709 1-126-972-11 ELECT 1000uF 20% 50V C710 1-126-969-11 ELECT 220uF 20% 50V C711 1-126-964-11 ELECT 10uF 20% 50V C715 1-164-159-11 CERAMIC 0.1uF 50V < CONNECTOR > CN702 1-770-831-11 CONNECTOR, BOARD TO BOARD 6P CN703 1-566-212-11 PIN, CONNECTOR 3P (EON CONTROL) < DIODE > D511 8-719-911-19 DIODE 1SS119-25 D512 8-719-911-19 DIODE 1SS119-25 D513 8-719-911-19 DIODE 1SS119-25 D700 8-719-024-99 DIODE 11ES2-NTA2B D701 8-719-024-99 DIODE 11ES2-NTA2B D702 8-719-024-99 DIODE 11ES2-NTA2B < IC > IC700 8-759-111-68 IC UPC1237HA < COIL > L501 1-411-906-11 COIL, AIR-CORE L601 1-411-906-11 COIL, AIR-CORE < TRANSISTOR > Q700 8-729-119-76 TRANSISTOR 2SA1175-HFE Q701 8-729-119-78 TRANSISTOR 2SC2785-HFE < RESISTOR > R528 1-249-162-11 CARBON 10 5% 1/3W R529 1-249-206-11 CARBON 680 5% 1/3W !R530 1-212-857-00 FUSIBLE 10 5% 1/4W !R531 1-212-857-00 FUSIBLE 10 5% 1/4W R628 1-249-162-11 CARBON 10 5% 1/3W R629 1-249-206-11 CARBON 680 5% 1/3W !R630 1-212-857-00 FUSIBLE 10 5% 1/4W !R631 1-212-857-00 FUSIBLE 10 5% 1/4W R700 1-249-431-11 CARBON 15K 5% 1/4W (FB720R) R700 1-249-434-11 CARBON 27K 5% 1/4W (FB820R) R701 1-249-429-11 CARBON 10K 5% 1/4W R702 1-249-429-11 CARBON 10K 5% 1/4W R703 1-259-476-11 CARBON 100K 5% 1/6W R704 1-249-433-11 CARBON 22K 5% 1/4W R705 1-247-883-00 CARBON 150K 5% 1/4W R706 1-249-431-11 CARBON 15K 5% 1/4W R707 1-249-429-11 CARBON 10K 5% 1/4W R710 1-247-231-00 CARBON 430 5% 1/2W (FB820R) R710 1-247-746-11 CARBON 390 5% 1/2W F (FB720R) R711 1-247-231-00 CARBON 430 5% 1/2W (FB820R) SIRCS SUB SP-TM The components identified by mark ! or dotted line with mark ! are critical for safety. Replace only with part number specified. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 35 – Ref. No. Part No. Description Remark VOL R711 1-247-746-11 CARBON 390 5% 1/2W F (FB720R) < RELAY > RY501 1-515-921-11 RELAY (12V) RY502 1-515-921-11 RELAY (12V) RY503 1-515-920-11 RELAY (24V) < TERMINAL > * TM501 1-537-699-11 TERMINAL BOARD (SP)(SPEAKERS) ************************************************************** * 1-669-496-11 VOL BOARD ********* < CAPACITOR > C310 1-136-165-00 FILM 0.1uF 5% 50V < CONNECTOR > CN302 1-691-772-11 PLUG (MICRO CONNECTOR) 10P CN303 1-691-768-11 PLUG (MICRO CONNECTOR) 6P < TRANSISTOR > Q300 8-729-141-26 TRANSISTOR 2SC3622A-LK Q400 8-729-141-26 TRANSISTOR 2SC3622A-LK < RESISTOR > R312 1-259-448-11 CARBON 6.8K 5% 1/6W R412 1-259-448-11 CARBON 6.8K 5% 1/6W < VARIABLE RESISTOR > RV300 1-225-227-11 RES, VAR, CARBON 120K/120K (VOLUME) ************************************************************** MISCELLANEOUS ************* !11 1-777-185-11 CORD, POWER !CNJ3 1-526-794-11 OUTLET, AC !CNJ4 1-526-794-11 OUTLET, AC Q511 8-729-232-45 TRANSISTOR 2SK1529-Y Q512 8-729-232-46 TRANSISTOR 2SJ200-Y Q611 8-729-232-45 TRANSISTOR 2SK1529-Y Q612 8-729-232-46 TRANSISTOR 2SJ200-Y Q702 8-729-209-15 TRANSISTOR 2SD2012 !S1 1-554-920-61 SWITCH, PUSH (AC POWER)(1 KEY)(U) !T1 1-431-870-11 TRANSFORMER, POWER (FB720R) !T1 1-431-872-11 TRANSFORMER, POWER (FB820R) ************************************************************** ACCESSORIES & PACKING MATERIALS ******************************* 1-473-656-11 REMOTE COMMANDER (RM-S316) 3-864-335-11 MANUAL, INSTRUCTION (ENGLISH,FRENCH,SPANISH,PORTUGUESE) The components identified by mark ! or dotted line with mark ! are critical for safety. Replace only with part number specified. 3-864-335-21 MANUAL, INSTRUCTION (GERMAN,DUTCH,SWEDISH,ITALIAN) 4-981-643-01 COVER, BATTERY (FOR RM-S316) ************************************************************** ************* HARDWARE LIST ************* #1 7-682-548-09 SCREW (3X8) #2 7-685-885-09 SCREW +BVTT 4X16 (S) Ref. No. Part No. Description Remark SP-TM www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 36 – TA-FB720R/FB820R Sony Corporation Home A&V Products Company 9-922-867-11 98E097541-1 Printed in Hungary © 1998. 5 Published by Quality Assurance Dept. (Shibaura) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com
