– 1 – MICROFILM US Model SPECIFICATIONS SERVICE MANUAL FM STEREO/FM-AM RECEIVER STR-V200 — Continued on next page — www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 2 – SAFETY-RELATED COMPONENT WARNING !! COMPONENTS IDENTIFIED BY MARK ! OR DOTTED LINE WITH MARK ! ON THE SCHEMATIC DIAGRAMS AND IN THE PARTS LIST ARE CRITICAL TO SAFE OPERATION. REPLACE THESE COMPONENTS WITH SONY PARTS WHOSE PART NUMBERS APPEAR AS SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUBLISHED BY SONY. Notes on chip component replacement • Never reuse a disconnected chip component. • Notice that the minus side of a tantalum capacitor may be damaged by heat. SAFETY CHECK-OUT After correcting the original service problem, perform the follow- ing safety checks before releasing the set to the customer: Check the antenna terminals, metal trim, “metallized” knobs, screws, and all other exposed metal parts for AC leakage. Check leakage as described below. LEAKAGE The AC leakage from any exposed metal part to earth Ground and from all exposed metal parts to any exposed metal part having a return to chassis, must not exceed 0.5 mA (500 microampers). Leak- age current can be measured by any one of three methods. 1. A commercial leakage tester, such as the Simpson 229 or RCA WT-540A. Follow the manufacturers’ instructions to use these instruments. 2. A battery-operated AC milliammeter. The Data Precision 245 digital multimeter is suitable for this job. 3. Measuring the voltage drop across a resistor by means of a VOM or battery-operated AC voltmeter. The “limit” indication is 0.75 V, so analog meters must have an accurate low-voltage scale. The Simpson 250 and Sanwa SH-63Trd are examples of a pas- sive VOM that is suitable. Nearly all battery operated digital multimeters that have a 2V AC range are suitable. (See Fig. A) Fig. A. Using an AC voltmeter to check AC leakage. 0.15µF To Exposed Metal Parts on Set 1.5kΩ AC voltmeter (0.75V) Earth Ground www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 3 – TABLE OF CONTENTS SECTION 1 SERVICING NOTE 1. SERVICING NOTE .......................................................... 3 2. GENERAL .......................................................................... 4 3. DIAGRAMS 3-1. Circuit Boards Location ........................................................ 6 3-2. Schematic Diagram – Main (1/3) Section – .......................... 7 3-3. Schematic Diagram – Main (2/3) Section – .......................... 9 3-4. Schematic Diagram – Main (3/3) Section – ........................ 11 3-5. Schematic Diagram – Display Section – ............................ 13 3-6. Schematic Diagram – Panel Section – ................................ 15 3-7. Printed Wiring Board – Main Section – .............................. 17 3-8. Printed Wiring Board – Power Section – ............................ 21 3-9. Printed Wiring Board – Display Section – .......................... 25 3-10. Printed Wiring Board – 10 Key Section – ........................ 29 3-11. Printed Wiring Board – Panel Section – ........................... 31 3-12. IC Pin Functions ............................................................... 33 3-13. IC Block Diagrams ........................................................... 35 FACTORY SET Mode which sets the preset settings of the unit to that at shipment. Procedure: While pressing the VIDEO button and TV/DBS button together, press the 1/u button to turn on the power. “FACTORY” will be displayed and factory settings executed. INITIALIZATION Mode which erases all the preset settings of the unit. Use this mode when returning the unit to the customer. Procedure: While pressing the VIDEO button, TV/DBS button, and TAPE/MD button together, press the 1/u button to turn on the power. “INITIAL” will be displayed and initialization executed. FLUORESCENT INDICATOR TUBE LIGHTING CHECK Mode which lights up the whole fluorescent indicator tube or partially. Procedure: While pressing the TV/DBS button and TAPE/MD button together, press the 1/u button to turn on the power. The fluorescent indicator tube will light up in about 0.5 seconds, and then start to light up partially. After partial lighting completes, the BASS BOOST indicator will light up, “FINISH” will be displayed, indicating that fluorescent indicator tube lighting check has completed. SWITCHING OF 9 kHz/10 kHz AM CHANNEL STEP The AM channels of this unit can be switched between 9 kHz and 10 kHz. Procedure: Set FUNCTION to AM and turn off the power. While pressing the TUNING + button, press the 1/u button to turn on the power. “9 k STEP” or “10 k STEP” will be displayed, and the channel step will be switched. 4. EXPLODED VIEWS 4-1. Case Section........................................................................ 37 4-2. Chassis Section ................................................................... 38 5. ELECTRICAL PARTS LIST ........................................ 39 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 4 – Front Panel Descriptions 7 8 2 3 4 6 5 SECTION 2 GENERAL 1 26 16 17 10 11 13 14 15 12 9 18 19 21 22 23 24 25 20 1 1/u button 2 VIDEO button 3 TV/DBS button 4 TAPE/MD button 5 CD button 6 TUNER button 7 BASS BOOST indicator 8 MASTER VOLUME knob 9 BALANCE knob 10 TREBLE knob 11 BASS knob 12 SURROUND ON/OFF button 13 SET UP button 14 EFFECT/DELAY TIME button 15 SURROUND MODE button 16 Numeral (1 to 0) button 17 Display window 18 DIRECT button 19 SHIFT button 20 MEMORY button 21 AM button 22 TUNING + button 23 FM button 24 TUNING – button 25 PHONES jack 26 SPEAKERS Ø ON/ø OFF button www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 5 – This section is extracted from instruction manual. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 6 – SECTION 3 DIAGRAMS 3-1. CIRCUIT BOARDS LOCATION THIS NOTE IS COMMON FOR PRINTED WIRING BOARDS AND SCHEMATIC DIAGRAMS. (In addition to this, the necessary note is printed in each block.) For schematic diagrams. Note: • All capacitors are in µF unless otherwise noted. pF: µµF 50 WV or less are not indicated except for electrolytics and tantalums. • All resistors are in Ω and 1/4 W or less unless otherwise specified. • ¢� : internal component. • 2 : nonflammable resistor. • C : panel designation. For printed wiring boards. Note: • X : parts extracted from the component side. • b : Pattern of the conductor side. • U : B+ Line. • V : B– Line. • Voltages and waveforms are dc with respect to ground under no-signal (detuned) conditions. no mark : FM WAVEFORMS 1� 2 IC201 #¢ X1 IC300 @¢ Note: The components identified by mark ! or dotted line with mark ! are critical for safety. Replace only with part number specified. • Indication of transistor C These are omitted E B 8MHz 4.8Vp-p 4.19MHz 5.4Vp-p Caution: Pattern face side: Parts on the pattern face side seen from (Conductor Side) the pattern face are indicated. Parts face side: Parts on the parts face side seen from (Component Side) the parts face are indicated. • Voltages are taken with a VOM (Input impedance 10 MΩ). Voltage variations may be noted due to normal produc- tion tolerances. • Waveforms are taken with a oscilloscope. Voltage variations may be noted due to normal produc- tion tolerances. • Circled numbers refer to waveforms. • Signal path. F� : FM SECONDARY board PRIMARY board STANDBY board MAIN board VOL-TONE board DISPLAY board SPEAKER SW board KEY board POWER SW board www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 7 – – 8 – STR-V200 3-2. SCHEMATIC DIAGRAM – MAIN (1/3) SECTION – • See page 6 for Waveforms. • See page 17 for Printed Wiring Board. • See page 33 for IC Pin Functions. • See page 35 for IC Block Diagrams. (Page 15) (Page 9) (Page 11) (Page 11) (Page 13) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 9 – – 10 – STR-V200 3-3. SCHEMATIC DIAGRAM – MAIN (2/3) SECTION – • See page 17 for Printed Wiring Board. • See page 35 for IC Block Diagrams. (Page 16) (Page 16) (Page 11) (Page 16) (Page 8) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 11 – – 12 – STR-V200 3-4. SCHEMATIC DIAGRAM – MAIN (3/3) SECTION – • See page 17 for Printed Wiring Board. • See page 35 for IC Block Diagrams. (Page 10) (Page 8) (Page 8) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 13 – – 14 – STR-V200 3-5. SCHEMATIC DIAGRAM – DISPLAY SECTION – • See page 6 for Waveforms. • See page 25 for Printed Wiring Board. • See page 35 for IC Block Diagrams. (Page 7) (Page 15) (Page 16) (Page 16) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 15 – – 16 – STR-V200 3-6. SCHEMATIC DIAGRAM – PANEL SECTION – • See page 31 for Printed Wiring Board. (Page 13) (Page 8) (Page 9) (Page 14) (Page 14) (Page 10) (Page 10) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 17 – – 18 – STR-V200 3-7. PRINTED WIRING BOARD – MAIN SECTION – • See page 6 for Circuit Boards Location. Ref. No. Location • Semiconductor Location D610 B-4 D710 I-3 D721 I-9 D722 I-9 D723 I-7 D724 I-8 D725 I-8 D801 J-6 D802 E-1 D804 I-1 D810 B-1 D811 B-1 D812 B-1 D813 B-1 D814 A-1 D815 A-1 D817 D-9 D818 C-1 D820 C-2 D821 C-2 D822 B-2 D823 B-2 D901 E-9 IC300 G-8 IC301 E-8 IC302 I-8 IC401 B-8 IC701 H-6 IC702 D-6 IC801 C-8 IC802 D-8 IC950 B-3 Q303 F-10 Q304 F-9 Q307 H-9 Q308 I-9 Q601 D-6 Q602 C-5 Q603 D-5 Q604 C-5 Q610 B-3 Q620 C-6 Q651 G-6 Q652 G-5 Q653 H-5 Q654 F-5 Q670 G-6 Q701 I-6 Q702 I-5 Q703 H-5 Q704 H-5 Q710 J-3 Q720 H-6 Q721 I-8 Q722 J-8 Q723 I-8 Q751 E-6 Q752 E-5 Q753 F-5 Q754 E-5 Q770 D-6 Q801 J-7 Q802 B-1 Q808 C-9 Q809 C-1 Q951 B-3 (Conductor Side) Note: Conductor side equal an inversion of component side. w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 19 – – 20 – STR-V200 (Component Side) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 21 – – 22 – STR-V200 3-8. PRINTED WIRING BOARD – POWER SECTION – • See page 6 for Circuit Boards Location. (Conductor Side) Note: Conductor side equal an inversion of component side. w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 23 – – 24 – STR-V200 (Component Side) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 25 – – 26 – STR-V200 3-9. PRINTED WIRING BOARD – DISPLAY SECTION – • See page 6 for Circuit Boards Location. (Conductor Side) Note: Conductor side equal an inversion of component side. w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 27 – – 28 – STR-V200 (Component Side) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 29 – – 30 – STR-V200 3-10. PRINTED WIRING BOARD – KEY SECTION – • See page 6 for Circuit Boards Location. (Conductor Side) Note: Conductor side equal an inversion of component side. (Component Side) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 31 – – 32 – STR-V200 3-11. PRINTED WIRING BOARD – PANEL SECTION – • See page 6 for Circuit Boards Location. (Conductor Side) Note: Conductor side equal an inversion of component side. (Component Side) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 33 – – 34 – Pin No. Pin Name I/O Function 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60 61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80 Pin No. Pin Name I/O Function • IC201 uPD78044FGF-064-3B9 3-12. IC PIN FUNCTIONS 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 O O O O O O O — I I I O O I I I I I I — O O O — I I I I — — — — — I O O O O O O Fluorescent indicator tube drive Power supply (+5V) System clock System data PLL data input from TU001 Chip enable output Chip enable output Input for model select (Connected to ground) Protector detect input Protector detect input System reset terminal Auto stop detect input Stereo detect input Ground (Not used) Speaker relay drive Surround Relay Power relay drive Ground A/D signal input terminal A/D3 key input terminal A/D2 key input terminal A/D1 key input terminal Power supply (+5V) Reference voltage (+5V) Ground Not used (Open) Ground System clock (4.19MHz) System clock (4.19MHz) Mute drive output for µPD2581V (IC701) Plologic LED (Not used) CINEMA STUDIO LED (Not used) HALL LED (Not used) Tuner mute drive output DIG7 DIG6 DIG5 DIG4 DIG3 DIG2 DIG1 +5V S. CLK S. DATA PLL. DATA S. CE (LC7288) S. CE (LV1010) REAR-R BRIDGE PROTECT RESET AUTO-STOP STEREO-IN AVSS SP-RY SURR-RY POWER-RY AVSS SIGNAL A/D3 A/D2 A/D1 AVDD AV. REF GND NC VSS X1 X2 IC. MUTE PROLOGIC SIMULATED HALL T. MUTE O O O I I I I — I I — — I O O I I I I I O O O O O O O O O O — O O O O O O O O O Volume up Volume down Standby LED drive (Not used) System power ON/OFF RDS data input (Not used) RDS clock input (Not used) Stop signal input from NJM2103D (IC950) Ground Sircs signal input Power switch input terminal 5.1ch LED drive Power supply (+5V) Bass boost LED drive Line mute drive SL mute drive Input for model select Key in 4 Key in 3 Key in 2 Key in 1 SR mute drive Not used Fluorescent indicator tube drive Connect to –24V Fluorescent indicator tube drive Fluorescent indicator tube drive VOLUME UP VOLUME DOWN STANDBY SYS. POWER RDS. DATA. IN RDS. CLK. IN STOP VSS SIRCS POWER SW 5.1ch LED +5V BASS BOOST FUNC. MUTE SL MUTE VERSION K14 K13 K12 K11 SR MUTE S15 S14 S13 S12 S11 S10 S9 S8 S7 VLOAD S6 S5 S4 S3 S2 S1 DIG10 DIG9 DIG8 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 35 – IC701, 702 uPC2581 PROTECTOR DRIVE 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 PRE DRIVE PRE DRIVE BIAS CIRCUIT REG DRIVE MUTE +VOUT1 –VOUT1 COMP1 NF1 IN1 GND IN2 NF2 COMP2 –VOUT2 +VOUT2 VCC1 VCC2 VEE 6-13. IC BLOCK DIAGRAMS • Main section IC300 LV1016 1 5 6 + – + 20 19 18 17 16 15 14 13 21 22 23 24 2 3 4 7 8 9 10 12 11 + DEC IN-FILTER (40kHz) VDD ADM-CONT SRAM ADM OUT-FILTER (7k/5k) B-NR DC-OUT VOL/MUTE S-TRIM INV-PHASE R+DELAY L+DELAY A B A B A B A B A B A B A B L–R L+R (–6dB) A B A.GND L-OUT R-OUT VREF S-OUT DELAY-OUT S-IN R-IN L-IN VCC NR-DET ENABLE DATA CLK D.GND DC-CUT VDD OSC OSC NR-IREF DC-CUT IC401 LC7822 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 CONTROL LATCH SHIFT RESISTOR LEVEL SHIFT CL DI CE VEE OUT IN OUT IN OUT IN VSS S RESET VDD OUT IN IN OUT IN OUT IN 1 2 3 4 5 6 7 8 V+ VSB/SESIN VSA RESET GND OUTC VSC CR VREF + – – + – + – + Q R S IC950 NJM2103D www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 36 – 1 2 3 4 5 6 7 8 9 15 10 11 12 + 13 14 16 21 18 19 25 17 24 22 23 20 34 32 33 29 30 35 28 31 27 26 36 40 39 38 37 41 42 NOISE FILTER NOISE CH BALANCE CONTROL VR CONTROL LPF V REF VR VR NOISE GENERATOR VCA VCA VCA VCA VCA VCA VCA VCA LPF LPF RECT RECT RECT RECT P. S. P. S. CMODE MUTE DIVIDER OSC CONTROL CTRIM LOG DIFF LOG DIFF DUAL T CONTROL L-IN R-IN VSS CLK DATA VCC L-OUT R-OUT S-OUT C-OUT ENABLE OSC1 CMODE-CAP. C-TRIM DC CUT R-BPF1 R-BPF2 R-BPF3 DC CUT DC CUT L-R RECT L+R RECT VCS-TH VCS-1 VCS-2 BPF1 BPF2 VREF S-CH DC OUT C-CH DC OUT L-CH DC OUT R-CH DC OUT VREF L-BPF1 L-BPF2 L-BPF3 DC CUT DC CUT R RECT L RECT VLR-TH VLR-1 VLR-2 + IC301 LA2786 • Display section IC202 BA6208 1 2 3 4 5 6 7 8 9 NC OUTPUT 2 Vcc GND NC INPUT 2 INPUT 1 NC MOTOR DRIVE MOTOR DRIVE REG SWITCH SWITCH OUTPUT1 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 37 – SECTION 4 EXPLODED VIEWS 4-1. CASE SECTION NOTE: • Items marked “*” are not stocked since they are seldom required for routine service. Some delay should be anticipated when ordering these items. • The mechanical parts with no reference number in the exploded views are not supplied. • Hardware (# mark) list and accessories and packing materials are given in the last of this parts list. Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark The components identified by mark ! or dotted line with mark ! are critical for safety. Replace only with part number specified. * 11 1-670-378-11 POWER SW BOARD * 12 A-4414-896-A VOL-TONE BOARD 13 1-782-074-11 WIRE (FLAT TYPE) (7 CORE) 14 1-782-075-11 WIRE (FLAT TYPE) (9 CORE) * 15 4-921-941-01 CUSHION (FL) * 16 4-210-383-01 HOLDER (FL TUBE) 17 3-704-366-31 SCREW (CASE) (M3X6) * 18 4-210-365-01 CASE FL201 1-517-662-11 INDICATOR TUBE, FLUORESCENT 1 A-4411-215-A KNOB ASSY 2 4-210-373-01 KNOB (EQ) 3 4-951-620-01 SCREW (2.6X8), +BVTP * 4 4-978-398-21 CUSHION 5 4-977-593-01 RING (DIA. 50), ORNAMENTAL 6 A-4411-214-A PANEL ASSY, FRONT 7 4-996-698-41 EMBLEM, SONY * 8 A-4414-899-A KEY BOARD 9 1-782-100-11 WIRE (FLAT TYPE) (23 CORE) * 10 A-4414-898-A DISPLAY BOARD, COMPLETE 1 2 4 5 6 7 8 10 11 12 3 3 3 3 14 13 17 17 17 18 15 15 16 9 Supplied with RV404 FL201 #2 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 38 – 4-2. CHASSIS SECTION Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 62 3-703-244-00 BUSHING (2104), CORD * 63 4-210-367-01 PANEL, BACK Q603 8-749-010-25 IC MN2488-OPY-M Q604 8-749-010-26 IC MP1620-OPY-M Q653 8-749-010-25 IC MN2488-OPY-M Q654 8-749-010-26 IC MP1620-OPY-M Q703 8-749-010-25 IC MN2488-OPY-M Q704 8-749-010-26 IC MP1620-OPY-M Q753 8-749-010-25 IC MN2488-OPY-M Q754 8-749-010-26 IC MP1620-OPY-M !T901 1-431-258-11 TRANSFORMER, POWER 51 X-4946-543-1 FOOT (SMALL) ASSY * 52 1-670-374-11 SPEAKER SW BOARD * 53 1-670-376-11 PRIMARY BOARD * 54 1-670-375-11 SECONDARY BOARD * 55 1-670-373-11 STANDBY BOARD !56 1-690-609-21 CORD, POWER 57 4-900-386-01 SCREW 58 4-210-380-01 RIVET, NYLON 59 3-905-609-01 SCREW (TRANSISTOR) * 60 4-978-398-21 CUSHION * 61 A-4414-900-A MAIN BOARD, COMPLETE The components identified by mark ! or dotted line with mark ! are critical for safety. Replace only with part number specified. 53 57 54 57 55 56 56 58 61 63 56 62 59 60 51 52 #1 not supplied not supplied #2 #2 #2 Q703 Q704 Q653 Q654 Q753 Q754 Q603 Q604 #2 #2 #2 #2 #2 #2 #2 #2 not supplied not supplied not supplied T901 #2 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 39 – • SEMICONDUCTORS In each case, u: µ , for example: uA...: µ A..., uPA...: µ PA..., uPB...: µ PB..., uPC...: µ PC..., uPD...: µ PD... • CAPACITORS uF : µ F • COILS uH : µ H • Due to standardization, replacements in the parts list may be different from the parts specified in the diagrams or the components used on the set. • -XX, -X mean standardized parts, so they may have some difference from the original one. • Items marked “*” are not stocked since they are seldom required for routine service. Some delay should be anticipated when ordering these items. • RESISTORS All resistors are in ohms METAL: Metal-film resistor METAL OXIDE: Metal Oxide-film resistor F : nonflammable SECTION 5 ELECTRICAL PARTS LIST Note: When indicating parts by reference number, please include the board name. Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark KEY The components identified by mark ! or dotted line with mark ! are critical for safety. Replace only with part number specified. * A-4414-899-A KEY BOARD, COMPLETE ******************** < CONNECTOR > * CNS205 1-580-169-11 PIN, CONNECTOR (PC BOARD) 8P < DIODE > D238 8-719-070-78 DIODE SEL6810A-TP6 (BASS BOOST) < RESISTOR > R237 1-249-421-11 CARBON 2.2K 5% 1/4W F R238 1-247-843-11 CARBON 3.3K 5% 1/4W R239 1-249-411-11 CARBON 330 5% 1/4W R240 1-249-413-11 CARBON 470 5% 1/4W F R241 1-249-415-11 CARBON 680 5% 1/4W F R242 1-249-417-11 CARBON 1K 5% 1/4W F R243 1-249-419-11 CARBON 1.5K 5% 1/4W F R244 1-249-426-11 CARBON 5.6K 5% 1/4W R246 1-249-411-11 CARBON 330 5% 1/4W R247 1-249-413-11 CARBON 470 5% 1/4W F R248 1-249-415-11 CARBON 680 5% 1/4W F R249 1-249-417-11 CARBON 1K 5% 1/4W F R280 1-249-419-11 CARBON 1.5K 5% 1/4W F R281 1-249-421-11 CARBON 2.2K 5% 1/4W F R282 1-247-843-11 CARBON 3.3K 5% 1/4W < SWITCH > S221 1-554-937-11 SWITCH, KEY BOARD (CD) S222 1-554-937-11 SWITCH, KEY BOARD (TUNER) S223 1-554-937-11 SWITCH, KEY BOARD (VIDEO) S224 1-554-937-11 SWITCH, KEY BOARD (6) S225 1-554-937-11 SWITCH, KEY BOARD (7) S226 1-554-937-11 SWITCH, KEY BOARD (8) S227 1-554-937-11 SWITCH, KEY BOARD (9) S228 1-554-937-11 SWITCH, KEY BOARD (0) S231 1-554-937-11 SWITCH, KEY BOARD (TV/DBS) S232 1-554-937-11 SWITCH, KEY BOARD (1) S233 1-554-937-11 SWITCH, KEY BOARD (2) S234 1-554-937-11 SWITCH, KEY BOARD (3) S235 1-554-937-11 SWITCH, KEY BOARD (4) S236 1-554-937-11 SWITCH, KEY BOARD (5) S237 1-554-937-11 SWITCH, KEY BOARD (DIRECT) S239 1-554-937-11 SWITCH, KEY BOARD (TAPE/MD) ************************************************************** * A-4414-898-A DISPLAY BOARD, COMPLETE *********************** * 4-210-383-01 HOLDER (FL TUBE) * 4-921-941-01 CUSHION (FL) < CAPACITOR > C201 1-104-905-11 CAPACITOR 0.22F 5.5V C202 1-164-159-21 CERAMIC 0.1uF 50V C203 1-124-465-00 ELECT 0.47uF 20% 50V C204 1-164-159-21 CERAMIC 0.1uF 50V C205 1-162-294-31 CERAMIC 0.001uF 10% 50V C206 1-164-159-21 CERAMIC 0.1uF 50V C207 1-126-096-11 ELECT 10uF 20% 35V C421 1-137-440-11 FILM 0.018uF 5% 50V C422 1-124-463-00 ELECT 0.1uF 20% 50V C423 1-137-368-11 FILM 0.0047uF 5% 50V C424 1-137-372-11 FILM 0.022uF 5% 50V C471 1-137-440-11 FILM 0.018uF 5% 50V C472 1-124-463-00 ELECT 0.1uF 20% 50V C473 1-137-368-11 FILM 0.0047uF 5% 50V C474 1-137-372-11 FILM 0.022uF 5% 50V < CONNECTOR > * CNP205 1-580-160-11 PIN, CONNECTOR (PC BOARD) 8P CNP301 1-566-690-11 PLUG, CONNECTOR (2.5MM) 2P CNS201 1-568-742-11 SOCKET, CONNECTOR 23P < DIODE > D201 8-719-911-19 DIODE 1SS119-25 D202 8-719-911-19 DIODE 1SS119-25 D203 8-719-911-19 DIODE 1SS119-25 D204 8-719-911-19 DIODE 1SS119-25 D213 8-719-911-19 DIODE 1SS119-25 D214 8-719-911-19 DIODE 1SS119-25 D225 8-719-911-19 DIODE 1SS119-25 D231 8-719-911-19 DIODE 1SS119-25 < FLUORESCENT INDICATOR > FL201 1-517-141-11 INDICATOR TUBE, FLUORESCENT < IC > IC201 8-759-479-19 IC uPD78044FGF-064-3B9 IC202 8-759-962-08 IC BA6208 IC203 8-759-339-53 IC GP1U28XB DISPLAY www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 40 – Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark < COIL > L401 1-410-509-11 INDUCTOR 10uH < TRANSISTOR > Q201 8-729-900-63 TRANSISTOR DTA124ES Q202 8-729-900-36 TRANSISTOR DTC124ES Q231 8-729-900-36 TRANSISTOR DTC124ES < RESISTOR > R200 1-247-863-91 CARBON 22K 5% 1/4W R201 1-247-903-00 CARBON 1M 5% 1/4W R202 1-249-429-11 CARBON 10K 5% 1/4W R203 1-249-429-11 CARBON 10K 5% 1/4W R204 1-249-425-11 CARBON 4.7K 5% 1/4W F R205 1-249-441-11 CARBON 100K 5% 1/4W R207 1-249-429-11 CARBON 10K 5% 1/4W R211 1-247-863-91 CARBON 22K 5% 1/4W R212 1-247-863-91 CARBON 22K 5% 1/4W R213 1-247-863-91 CARBON 22K 5% 1/4W R214 1-247-863-91 CARBON 22K 5% 1/4W R216 1-247-863-91 CARBON 22K 5% 1/4W R221 1-247-807-31 CARBON 100 5% 1/4W R222 1-247-807-31 CARBON 100 5% 1/4W R223 1-247-807-31 CARBON 100 5% 1/4W R224 1-247-807-31 CARBON 100 5% 1/4W R225 1-247-807-31 CARBON 100 5% 1/4W R226 1-249-441-11 CARBON 100K 5% 1/4W R227 1-249-441-11 CARBON 100K 5% 1/4W R228 1-249-412-11 CARBON 390 5% 1/4W F R231 1-249-427-11 CARBON 6.8K 5% 1/4W F R232 1-249-411-11 CARBON 330 5% 1/4W R233 1-249-413-11 CARBON 470 5% 1/4W F R234 1-249-415-11 CARBON 680 5% 1/4W F R235 1-249-417-11 CARBON 1K 5% 1/4W F R236 1-249-419-11 CARBON 1.5K 5% 1/4W F R270 1-247-807-31 CARBON 100 5% 1/4W R283 1-249-427-11 CARBON 6.8K 5% 1/4W F R284 1-249-427-11 CARBON 6.8K 5% 1/4W F R286 1-249-437-11 CARBON 47K 5% 1/4W R420 1-249-415-11 CARBON 680 5% 1/4W F R421 1-249-430-11 CARBON 12K 5% 1/4W R422 1-249-422-11 CARBON 2.7K 5% 1/4W F R423 1-247-903-00 CARBON 1M 5% 1/4W R424 1-247-903-00 CARBON 1M 5% 1/4W R470 1-249-415-11 CARBON 680 5% 1/4W F R471 1-249-430-11 CARBON 12K 5% 1/4W R472 1-249-422-11 CARBON 2.7K 5% 1/4W F R473 1-247-903-00 CARBON 1M 5% 1/4W R474 1-247-903-00 CARBON 1M 5% 1/4W < VARIABLE RESISTOR > RV421 1-225-660-11 RES, VAR 100K/100K (BASS) RV422 1-225-659-11 RES, VAR 125K/125K (TREBLE) RV423 1-225-658-11 RES, VAR 100K/100K (BALANCE) < SWITCH > S209 1-554-937-11 SWITCH, KEY BOARD (TUNING –) S210 1-554-937-11 SWITCH, KEY BOARD (TUNING +) S214 1-554-937-11 SWITCH, KEY BOARD (FM) S215 1-554-937-11 SWITCH, KEY BOARD (AM) S216 1-554-937-11 SWITCH, KEY BOARD (MEMORY) S217 1-554-937-11 SWITCH, KEY BOARD (SURROUND ON/OFF) S218 1-554-937-11 SWITCH, KEY BOARD (SET UP) S219 1-554-937-11 SWITCH, KEY BOARD (EFFECT, DELAY TIME) S229 1-554-937-11 SWITCH, KEY BOARD (SHIFT) S238 1-554-937-11 SWITCH, KEY BOARD (SURROUND MODE) < VIBRATOR > X201 1-577-101-11 VIBRATOR, CERAMIC (4.19MHz) ************************************************************** * A-4414-900-A MAIN BOARD, COMPLETE ******************** 3-905-609-01 SCREW (TRANSISTOR) 4-210-380-01 RIVET, NYLON 7-685-872-09 SCREW +BVTT 3X8 (S) < CAPACITOR > C302 1-126-934-11 ELECT 220uF 20% 16V C303 1-130-494-11 MYLAR 0.082uF 5% 50V C304 1-137-367-11 FILM 0.0033uF 5% 50V C305 1-130-494-11 MYLAR 0.082uF 5% 50V C306 1-126-959-11 ELECT 0.47uF 20% 50V C307 1-126-964-11 ELECT 10uF 20% 50V C308 1-126-964-11 ELECT 10uF 20% 50V C309 1-162-291-31 CERAMIC 560PF 10% 50V C310 1-126-962-11 ELECT 3.3uF 20% 50V C311 1-126-961-11 ELECT 2.2uF 20% 50V C312 1-126-934-11 ELECT 220uF 20% 16V C313 1-126-934-11 ELECT 220uF 20% 16V C314 1-136-165-00 FILM 0.1uF 5% 50V C316 1-124-252-00 ELECT 0.33uF 20% 50V C317 1-126-933-11 ELECT 100uF 20% 16V C318 1-136-357-11 FILM 680PF 5% 50V C322 1-126-962-11 ELECT 3.3uF 20% 50V C323 1-136-173-00 FILM 0.47uF 5% 50V C324 1-126-967-11 ELECT 47uF 20% 16V C325 1-136-165-00 FILM 0.1uF 5% 50V C326 1-136-165-00 FILM 0.1uF 5% 50V C327 1-126-959-11 ELECT 0.47uF 20% 50V C328 1-126-963-11 ELECT 4.7uF 20% 50V C329 1-126-959-11 ELECT 0.47uF 20% 50V C330 1-126-963-11 ELECT 4.7uF 20% 50V C331 1-124-250-11 ELECT 0.15uF 20% 50V C332 1-126-962-11 ELECT 3.3uF 20% 50V C333 1-124-250-11 ELECT 0.15uF 20% 50V C334 1-137-372-11 FILM 0.022uF 5% 50V C335 1-136-161-00 FILM 0.047uF 5% 50V C336 1-126-934-11 ELECT 220uF 20% 16V C337 1-126-964-11 ELECT 10uF 20% 50V C338 1-126-964-11 ELECT 10uF 20% 50V C339 1-126-964-11 ELECT 10uF 20% 50V C340 1-126-964-11 ELECT 10uF 20% 50V C341 1-126-934-11 ELECT 220uF 20% 16V DISPLAY MAIN www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 41 – Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark MAIN C342 1-126-962-11 ELECT 3.3uF 20% 50V C343 1-126-962-11 ELECT 3.3uF 20% 50V C344 1-136-165-00 FILM 0.1uF 5% 50V C345 1-136-165-00 FILM 0.1uF 5% 50V C346 1-126-959-11 ELECT 0.47uF 20% 50V C347 1-126-963-11 ELECT 4.7uF 20% 50V C348 1-126-959-11 ELECT 0.47uF 20% 50V C349 1-126-963-11 ELECT 4.7uF 20% 50V C350 1-124-250-11 ELECT 0.15uF 20% 50V C351 1-126-962-11 ELECT 3.3uF 20% 50V C352 1-124-250-11 ELECT 0.15uF 20% 50V C353 1-164-159-21 CERAMIC 0.1uF 50V C354 1-164-159-21 CERAMIC 0.1uF 50V C355 1-164-159-21 CERAMIC 0.1uF 50V C356 1-164-159-21 CERAMIC 0.1uF 50V C357 1-164-159-21 CERAMIC 0.1uF 50V C359 1-126-963-11 ELECT 4.7uF 20% 50V C360 1-126-963-11 ELECT 4.7uF 20% 50V C363 1-164-159-21 CERAMIC 0.1uF 50V C365 1-126-966-11 ELECT 33uF 20% 16V C366 1-164-159-21 CERAMIC 0.1uF 50V C406 1-164-159-21 CERAMIC 0.1uF 50V C408 1-162-294-31 CERAMIC 0.001uF 10% 50V C412 1-162-291-31 CERAMIC 560PF 10% 50V C413 1-164-159-21 CERAMIC 0.1uF 50V C415 1-164-159-21 CERAMIC 0.1uF 50V C416 1-164-159-21 CERAMIC 0.1uF 50V C434 1-162-286-21 CERAMIC 220PF 10% 50V C435 1-162-286-21 CERAMIC 220PF 10% 50V C602 1-162-282-31 CERAMIC 100PF 10% 50V C603 1-104-665-11 ELECT 100uF 20% 10V C605 1-102-233-00 CERAMIC 33PF 10% 500V C610 1-126-967-11 ELECT 47uF 20% 16V C611 1-137-372-11 FILM 0.022uF 5% 50V C620 1-162-286-21 CERAMIC 220PF 10% 50V C652 1-162-282-31 CERAMIC 100PF 10% 50V C653 1-104-665-11 ELECT 100uF 20% 10V C655 1-102-233-00 CERAMIC 33PF 10% 500V C660 1-126-967-11 ELECT 47uF 20% 16V C661 1-137-372-11 FILM 0.022uF 5% 50V C670 1-162-286-21 CERAMIC 220PF 10% 50V C702 1-162-282-31 CERAMIC 100PF 10% 50V C703 1-104-665-11 ELECT 100uF 20% 10V C705 1-102-233-00 CERAMIC 33PF 10% 500V C710 1-126-967-11 ELECT 47uF 20% 16V C711 1-137-372-11 FILM 0.022uF 5% 50V C720 1-162-286-21 CERAMIC 220PF 10% 50V C721 1-126-934-11 ELECT 220uF 20% 10V C722 1-126-964-11 ELECT 10uF 20% 50V C740 1-128-562-11 ELECT 47uF 20% 100V C741 1-128-562-11 ELECT 47uF 20% 100V C742 1-126-925-11 ELECT 470uF 20% 10V C743 1-126-925-11 ELECT 470uF 20% 10V C752 1-162-282-31 CERAMIC 100PF 10% 50V C753 1-104-665-11 ELECT 100uF 20% 10V C755 1-102-233-00 CERAMIC 33PF 10% 500V C760 1-126-967-11 ELECT 47uF 20% 16V C761 1-137-372-11 FILM 0.022uF 5% 50V C770 1-162-286-21 CERAMIC 220PF 10% 50V C801 1-104-664-11 ELECT 47uF 20% 25V C802 1-104-664-11 ELECT 47uF 20% 25V C803 1-107-766-11 ELECT(BLOCK) 8200uF 20% 71V C804 1-107-766-11 ELECT(BLOCK) 8200uF 20% 71V C805 1-137-420-11 FILM 0.047uF 10% 100V C806 1-137-420-11 FILM 0.047uF 10% 100V C807 1-104-664-11 ELECT 47uF 20% 25V C808 1-104-664-11 ELECT 47uF 20% 25V C809 1-126-960-11 ELECT 1uF 20% 50V C810 1-126-960-11 ELECT 1uF 20% 50V C811 1-126-942-61 ELECT 1000uF 20% 25V C812 1-126-942-61 ELECT 1000uF 20% 25V C813 1-101-001-00 CERAMIC 0.001uF 50V C814 1-101-001-00 CERAMIC 0.001uF 50V C820 1-161-494-00 CERAMIC 0.022uF 25V C821 1-161-494-00 CERAMIC 0.022uF 25V C822 1-104-664-11 ELECT 47uF 20% 25V C823 1-104-664-11 ELECT 47uF 20% 25V C950 1-126-767-11 ELECT 1000uF 20% 16V C951 1-164-097-11 CERAMIC 0.022uF 50V C952 1-126-960-11 ELECT 1uF 20% 50V C953 1-124-464-11 ELECT 0.22uF 20% 50V C954 1-126-096-11 ELECT 10uF 20% 35V C955 1-164-159-21 CERAMIC 0.1uF 50V < CONNECTOR > * CN706 1-764-321-11 PIN, CONNECTOR (PC BOARD) 4P CNP702 1-764-474-11 PIN, CONNECTOR (PC BOARD) 5P CNS204 1-568-742-11 SOCKET, CONNECTOR 23P CNS301 1-568-442-11 SOCKET, CONNECTOR 9P CNS701 1-568-439-11 SOCKET, CONNECTOR 7P * CNS802 1-564-778-11 PLUG, CONNECTOR (2.5MM) 4P < DIODE > D610 8-719-911-19 DIODE 1SS119-25 D710 8-719-911-19 DIODE 1SS119-25 D721 8-719-815-85 DIODE 1S1585 D722 8-719-815-85 DIODE 1S1585 D723 8-719-911-19 DIODE 1SS119-25 D724 8-719-911-19 DIODE 1SS119-25 D725 8-719-911-19 DIODE 1SS119-25 D801 8-719-936-37 DIODE HZS24-1LTD D802 8-719-302-38 DIODE RBV-602-01 D804 8-719-923-38 DIODE MTZJ-T-77-5.6B D810 8-719-200-82 DIODE 11ES2 D811 8-719-200-82 DIODE 11ES2 D812 8-719-200-82 DIODE 11ES2 D813 8-719-200-82 DIODE 11ES2 D814 8-719-911-19 DIODE 1SS119-25 D815 8-719-911-19 DIODE 1SS119-25 D817 8-719-001-30 DIODE UZL-9H3 D818 8-719-911-19 DIODE 1SS119-25 D820 8-719-200-82 DIODE 11ES2 D821 8-719-200-82 DIODE 11ES2 D822 8-719-200-82 DIODE 11ES2 D823 8-719-200-82 DIODE 11ES2 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 42 – Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark MAIN D901 8-719-911-19 DIODE 1SS119-25 < EARTH > * G201 1-537-738-21 TERMINAL, EARTH * G202 1-537-738-21 TERMINAL, EARTH * G203 1-537-738-21 TERMINAL, EARTH < IC > IC300 8-759-442-97 IC LV1016 IC301 8-759-442-96 IC LA2786 IC302 8-759-636-74 IC M5218AP-22 IC401 8-759-805-14 IC LC7822 IC701 8-759-326-52 IC uPC2581V IC702 8-759-326-52 IC uPC2581V IC801 8-759-231-58 IC TA7812S IC802 8-759-604-45 IC M5F79M12L IC950 8-759-333-83 IC NJM2103D < JACK > J401 1-774-843-11 JACK, PIN 1P (MIX AUDIO OUT) J402 1-774-005-21 JACK, PIN 6P (TAPE/MD, CD) J403 1-770-615-21 JACK, PIN 6P (VIDEO, TV/DBS) < COIL > L301 1-410-509-11 INDUCTOR 10uH L302 1-410-509-11 INDUCTOR 10uH L601 1-420-872-00 COIL, AIR-CORE L651 1-420-872-00 COIL, AIR-CORE L701 1-420-872-00 COIL, AIR-CORE L751 1-420-872-00 COIL, AIR-CORE < TRANSISTOR > Q303 8-729-141-30 TRANSISTOR 2SC3623A-LK Q304 8-729-141-30 TRANSISTOR 2SC3623A-LK Q307 8-729-141-30 TRANSISTOR 2SC3623A-LK Q308 8-729-141-30 TRANSISTOR 2SC3623A-LK Q601 8-729-119-76 TRANSISTOR 2SA1175-HFE Q602 8-729-141-30 TRANSISTOR 2SC3623A-LK Q603 8-749-010-25 IC MN2488-OPY-M Q604 8-749-010-26 IC MP1620-OPY-M Q610 8-729-119-78 TRANSISTOR 2SC2785-HFE Q620 8-729-140-82 TRANSISTOR 2SA988-PAFAEA Q651 8-729-119-76 TRANSISTOR 2SA1175-HFE Q652 8-729-141-30 TRANSISTOR 2SC3623A-LK Q653 8-749-010-25 IC MN2488-OPY-M Q654 8-749-010-26 IC MP1620-OPY-M Q670 8-729-140-82 TRANSISTOR 2SA988-PAFAEA Q701 8-729-119-76 TRANSISTOR 2SA1175-HFE Q702 8-729-141-30 TRANSISTOR 2SC3623A-LK Q703 8-749-010-25 IC MN2488-OPY-M Q704 8-749-010-26 IC MP1620-OPY-M Q710 8-729-119-78 TRANSISTOR 2SC2785-HFE Q720 8-729-140-82 TRANSISTOR 2SA988-PAFAEA Q721 8-729-140-82 TRANSISTOR 2SA988-PAFAEA Q722 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA Q723 8-729-119-78 TRANSISTOR 2SC2785-HFE Q751 8-729-119-76 TRANSISTOR 2SA1175-HFE Q752 8-729-141-30 TRANSISTOR 2SC3623A-LK Q753 8-749-010-25 IC MN2488-OPY-M Q754 8-749-010-26 IC MP1620-OPY-M Q770 8-729-140-82 TRANSISTOR 2SA988-PAFAEA Q801 8-729-140-97 TRANSISTOR 2SB734-34 Q802 8-729-119-78 TRANSISTOR 2SC2785-HFE Q808 8-729-180-92 TRANSISTOR 2SD809-K Q809 8-729-119-78 TRANSISTOR 2SC2785-HFE Q951 8-729-026-68 TRANSISTOR 2SD2525(TP) < RESISTOR > !R298 1-249-387-11 CARBON 3.3 5% 1/4W F !R299 1-249-387-11 CARBON 3.3 5% 1/4W F R300 1-247-903-00 CARBON 1M 5% 1/4W R301 1-249-421-11 CARBON 2.2K 5% 1/4W F R302 1-249-421-11 CARBON 2.2K 5% 1/4W F R303 1-249-439-11 CARBON 68K 5% 1/4W R304 1-249-441-11 CARBON 100K 5% 1/4W R306 1-249-436-11 CARBON 39K 5% 1/4W R307 1-247-862-11 CARBON 20K 5% 1/4W R308 1-249-421-11 CARBON 2.2K 5% 1/4W F R309 1-249-421-11 CARBON 2.2K 5% 1/4W F R352 1-249-441-11 CARBON 100K 5% 1/4W R353 1-249-425-11 CARBON 4.7K 5% 1/4W F R354 1-249-425-11 CARBON 4.7K 5% 1/4W F R355 1-249-425-11 CARBON 4.7K 5% 1/4W F R356 1-249-425-11 CARBON 4.7K 5% 1/4W F R357 1-249-441-11 CARBON 100K 5% 1/4W R358 1-249-441-11 CARBON 100K 5% 1/4W R359 1-249-425-11 CARBON 4.7K 5% 1/4W F R360 1-247-843-11 CARBON 3.3K 5% 1/4W R361 1-249-429-11 CARBON 10K 5% 1/4W R362 1-249-429-11 CARBON 10K 5% 1/4W R363 1-249-411-11 CARBON 330 5% 1/4W R402 1-249-421-11 CARBON 2.2K 5% 1/4W F R403 1-249-417-11 CARBON 1K 5% 1/4W F R404 1-249-417-11 CARBON 1K 5% 1/4W F R405 1-249-417-11 CARBON 1K 5% 1/4W F R406 1-249-417-11 CARBON 1K 5% 1/4W F R407 1-249-417-11 CARBON 1K 5% 1/4W F R408 1-249-429-11 CARBON 10K 5% 1/4W R409 1-249-417-11 CARBON 1K 5% 1/4W F R414 1-249-425-11 CARBON 4.7K 5% 1/4W F R415 1-249-417-11 CARBON 1K 5% 1/4W F R420 1-249-441-11 CARBON 100K 5% 1/4W R435 1-249-418-11 CARBON 1.2K 5% 1/4W F R442 1-249-418-11 CARBON 1.2K 5% 1/4W F R443 1-249-418-11 CARBON 1.2K 5% 1/4W F R447 1-249-416-11 CARBON 820 5% 1/4W F R448 1-249-429-11 CARBON 10K 5% 1/4W R449 1-247-863-91 CARBON 22K 5% 1/4W R452 1-249-421-11 CARBON 2.2K 5% 1/4W F R453 1-249-417-11 CARBON 1K 5% 1/4W F R454 1-249-417-11 CARBON 1K 5% 1/4W F R455 1-249-417-11 CARBON 1K 5% 1/4W F R456 1-249-417-11 CARBON 1K 5% 1/4W F R457 1-249-417-11 CARBON 1K 5% 1/4W F R458 1-249-429-11 CARBON 10K 5% 1/4W The components identified by mark ! or dotted line with mark ! are critical for safety. Replace only with part number specified. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 43 – Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark MAIN R459 1-249-417-11 CARBON 1K 5% 1/4W F R465 1-249-417-11 CARBON 1K 5% 1/4W F R470 1-249-441-11 CARBON 100K 5% 1/4W R601 1-249-417-11 CARBON 1K 5% 1/4W F R602 1-249-439-11 CARBON 68K 5% 1/4W R603 1-249-413-11 CARBON 470 5% 1/4W F R604 1-249-439-11 CARBON 68K 5% 1/4W R605 1-249-441-11 CARBON 100K 5% 1/4W R610 1-249-421-11 CARBON 2.2K 5% 1/4W F R611 1-249-437-11 CARBON 47K 5% 1/4W R613 1-249-414-11 CARBON 560 5% 1/4W F !R614 1-249-408-11 CARBON 180 5% 1/4W F !R615 1-249-408-11 CARBON 180 5% 1/4W F !R616 1-233-352-21 ENCAPSULATED COMPONENT !R617 1-249-393-11 CARBON 10 5% 1/4W F R618 1-249-389-11 CARBON 4.7 5% 1/4W F !R619 1-249-405-11 CARBON 100 5% 1/4W F R620 1-249-419-11 CARBON 1.5K 5% 1/4W F R621 1-249-426-11 CARBON 5.6K 5% 1/4W !R622 1-249-403-11 CARBON 68 5% 1/4W F R623 1-249-437-11 CARBON 47K 5% 1/4W R630 1-249-426-11 CARBON 5.6K 5% 1/4W R631 1-247-887-00 CARBON 220K 5% 1/4W R632 1-249-426-11 CARBON 5.6K 5% 1/4W R651 1-249-417-11 CARBON 1K 5% 1/4W F R652 1-249-439-11 CARBON 68K 5% 1/4W R653 1-249-413-11 CARBON 470 5% 1/4W F R654 1-249-439-11 CARBON 68K 5% 1/4W R655 1-249-441-11 CARBON 100K 5% 1/4W R660 1-249-421-11 CARBON 2.2K 5% 1/4W F R661 1-249-437-11 CARBON 47K 5% 1/4W R663 1-249-414-11 CARBON 560 5% 1/4W F !R664 1-249-408-11 CARBON 180 5% 1/4W F !R665 1-249-408-11 CARBON 180 5% 1/4W F !R666 1-233-352-21 ENCAPSULATED COMPONENT !R667 1-249-393-11 CARBON 10 5% 1/4W F R668 1-249-389-11 CARBON 4.7 5% 1/4W F R670 1-249-419-11 CARBON 1.5K 5% 1/4W F R671 1-249-426-11 CARBON 5.6K 5% 1/4W R672 1-249-431-11 CARBON 15K 5% 1/4W R673 1-249-437-11 CARBON 47K 5% 1/4W R701 1-249-417-11 CARBON 1K 5% 1/4W F R702 1-249-439-11 CARBON 68K 5% 1/4W R703 1-249-413-11 CARBON 470 5% 1/4W F R704 1-249-439-11 CARBON 68K 5% 1/4W R705 1-249-441-11 CARBON 100K 5% 1/4W R710 1-249-421-11 CARBON 2.2K 5% 1/4W F R711 1-249-437-11 CARBON 47K 5% 1/4W R713 1-249-414-11 CARBON 560 5% 1/4W F !R714 1-249-408-11 CARBON 180 5% 1/4W F !R715 1-249-408-11 CARBON 180 5% 1/4W F !R716 1-233-352-21 ENCAPSULATED COMPONENT !R717 1-249-393-11 CARBON 10 5% 1/4W F R718 1-249-389-11 CARBON 4.7 5% 1/4W F !R719 1-249-405-11 CARBON 100 5% 1/4W F R720 1-249-419-11 CARBON 1.5K 5% 1/4W F R721 1-249-426-11 CARBON 5.6K 5% 1/4W !R722 1-249-403-11 CARBON 68 5% 1/4W F R723 1-249-437-11 CARBON 47K 5% 1/4W R724 1-249-425-11 CARBON 4.7K 5% 1/4W F R725 1-249-429-11 CARBON 10K 5% 1/4W R726 1-249-417-11 CARBON 1K 5% 1/4W F R727 1-249-427-11 CARBON 6.8K 5% 1/4W F R730 1-249-429-11 CARBON 10K 5% 1/4W R731 1-247-887-00 CARBON 220K 5% 1/4W R734 1-249-429-11 CARBON 10K 5% 1/4W !R740 1-249-393-11 CARBON 10 5% 1/4W F !R741 1-249-393-11 CARBON 10 5% 1/4W F R742 1-249-425-11 CARBON 4.7K 5% 1/4W F R743 1-249-425-11 CARBON 4.7K 5% 1/4W F R751 1-249-417-11 CARBON 1K 5% 1/4W F R752 1-249-439-11 CARBON 68K 5% 1/4W R753 1-249-413-11 CARBON 470 5% 1/4W F R754 1-249-439-11 CARBON 68K 5% 1/4W R755 1-249-441-11 CARBON 100K 5% 1/4W R760 1-249-421-11 CARBON 2.2K 5% 1/4W F R761 1-249-437-11 CARBON 47K 5% 1/4W R763 1-249-414-11 CARBON 560 5% 1/4W F !R764 1-249-408-11 CARBON 180 5% 1/4W F !R765 1-249-408-11 CARBON 180 5% 1/4W F !R766 1-233-352-21 ENCAPSULATED COMPONENT !R767 1-249-393-11 CARBON 10 5% 1/4W F R768 1-249-389-11 CARBON 4.7 5% 1/4W F R770 1-249-419-11 CARBON 1.5K 5% 1/4W F R771 1-249-426-11 CARBON 5.6K 5% 1/4W R772 1-249-431-11 CARBON 15K 5% 1/4W R773 1-249-437-11 CARBON 47K 5% 1/4W R781 1-247-887-00 CARBON 220K 5% 1/4W !R803 1-247-739-11 CARBON 100 5% 1/2W F R804 1-249-425-11 CARBON 4.7K 5% 1/4W F R821 1-249-437-11 CARBON 47K 5% 1/4W R822 1-249-425-11 CARBON 4.7K 5% 1/4W F R823 1-249-437-11 CARBON 47K 5% 1/4W R824 1-249-425-11 CARBON 4.7K 5% 1/4W F R825 1-249-407-11 CARBON 150 5% 1/4W F !R830 1-249-405-11 CARBON 100 5% 1/4W F !R831 1-249-403-11 CARBON 68 5% 1/4W F R950 1-249-421-11 CARBON 2.2K 5% 1/4W F R951 1-249-429-11 CARBON 10K 5% 1/4W R952 1-247-843-11 CARBON 3.3K 5% 1/4W R953 1-247-863-91 CARBON 22K 5% 1/4W R954 1-249-439-11 CARBON 68K 5% 1/4W R955 1-249-429-11 CARBON 10K 5% 1/4W R956 1-247-843-11 CARBON 3.3K 5% 1/4W R957 1-249-417-11 CARBON 1K 5% 1/4W F R960 1-249-429-11 CARBON 10K 5% 1/4W R961 1-249-401-11 CARBON 47 5% 1/4W F < RELAY > RY601 1-515-921-11 RELAY (12V) RY701 1-515-921-11 RELAY (12V) RY801 1-755-013-11 RELAY < TERMINAL > TM001 1-537-240-51 TERMINAL BOARD (CHECKER PIN)(ANTENNA) TM601 1-537-923-11 TERMINAL BOARD (SPEAKER) (6P) (SPEAKER REAR/CENTER) The components identified by mark ! or dotted line with mark ! are critical for safety. Replace only with part number specified. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 44 – Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark MAIN TM701 1-537-240-11 TERMINAL BOARD (CHECKER PIN) (SPEAKER FRONT) < TUNER > TU001 1-233-593-11 ENCAPSULATED COMPONENT < VIBRATOR > X301 1-579-952-21 VIBRATOR, CERAMIC (8MHz) ************************************************************** * 1-670-378-11 POWER SW BOARD **************** < SWITCH > S200 1-554-937-11 SWITCH, KEY BOARD (1/u) ************************************************************** * 1-670-376-11 PRIMARY BOARD ************** 1-533-233-21 HOLDER, FUSE < FUSE > !F901 1-576-109-11 FUSE (5A 125V) < TRANSFORMER > !T901 1-431-285-31 TRANSFORMER POWER ************************************************************** * 1-670-375-11 SECONDARY BOARD ***************** < CONNECTOR > CNP801 1-764-480-11 PIN, CONNECTOR (PC BOARD) 11P < RESISTOR > !R810 1-249-381-11 CARBON 1 5% 1/4W F !R811 1-249-381-11 CARBON 1 5% 1/4W F ************************************************************** * 1-670-374-11 SPEAKER SW BOARD ****************** < JACK > J741 1-750-733-11 JACK (LARGE TYPE)(PHONES) < RESISTOR > R732 1-247-753-11 CARBON 1.2K 5% 1/2W R733 1-247-753-11 CARBON 1.2K 5% 1/2W R782 1-247-753-11 CARBON 1.2K 5% 1/2W R783 1-247-753-11 CARBON 1.2K 5% 1/2W < SWITCH > S701 1-771-436-11 SWITCH, PUSH (SPEAKERS) ************************************************************** * 1-670-373-11 STANDBY BOARD ************** < CONNECTOR > !CNJ902 1-540-057-11 OUTLET, AC (POLAR)(AC OUTLET) CNP901 1-564-321-00 PIN, CONNECTOR 2P < DIODE > D816 8-719-911-19 DIODE 1SS119-25 < EARTH > * G900 1-537-738-21 TERMINAL, EARTH < RESISTOR > !R901 1-202-725-00 SOLID 3.3M 10% 1/2W < RELAY > !RY901 1-515-720-11 RELAY < TRANSFORMER > !T902 1-450-361-11 TRANSFORMER, POWER ************************************************************** * A-4414-896-A VOL-TONE BOARD ************** < CAPACITOR > C420 1-162-207-31 CERAMIC 22PF 5% 50V C425 1-126-795-11 ELECT 10uF 20% 25V C426 1-126-795-11 ELECT 10uF 20% 25V C427 1-124-252-00 ELECT 0.33uF 20% 50V C428 1-130-489-00 MYLAR 0.033uF 5% 50V C429 1-102-973-00 CERAMIC 100PF 5% 50V C430 1-126-301-11 ELECT 1uF 20% 50V C431 1-126-301-11 ELECT 1uF 20% 50V C432 1-126-795-11 ELECT 10uF 20% 25V C433 1-126-795-11 ELECT 10uF 20% 25V C470 1-162-207-31 CERAMIC 22PF 5% 50V C475 1-126-795-11 ELECT 10uF 20% 25V C476 1-126-795-11 ELECT 10uF 20% 25V C477 1-124-252-00 ELECT 0.33uF 20% 50V C478 1-130-489-00 MYLAR 0.033uF 5% 50V C479 1-102-973-00 CERAMIC 100PF 5% 50V C492 1-124-464-11 ELECT 0.22uF 20% 50V C601 1-126-163-11 ELECT 4.7uF 20% 50V C651 1-126-163-11 ELECT 4.7uF 20% 50V C701 1-126-163-11 ELECT 4.7uF 20% 50V C751 1-126-163-11 ELECT 4.7uF 20% 50V < CONNECTOR > CNS402 1-568-439-11 SOCKET, CONNECTOR 7P CNS403 1-568-442-11 SOCKET, CONNECTOR 9P < DIODE > D421 8-719-911-19 DIODE 1SS119-25 PRIMARY POWER SW SECONDARY STANDBY SPEAKER SW VOL-TONE The components identified by mark ! or dotted line with mark ! are critical for safety. Replace only with part number specified. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 45 – Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark The components identified by mark ! or dotted line with mark ! are critical for safety. Replace only with part number specified. < IC > IC404 8-759-636-74 IC M5218AP-22 < TRANSISTOR > Q401 8-729-202-67 TRANSISTOR 2SK246-GR3 Q402 8-729-141-30 TRANSISTOR 2SC3623A-LK Q451 8-729-202-67 TRANSISTOR 2SK246-GR3 Q452 8-729-141-30 TRANSISTOR 2SC3623A-LK < RESISTOR > R425 1-249-429-11 CARBON 10K 5% 1/4W R426 1-249-439-11 CARBON 68K 5% 1/4W R427 1-249-417-11 CARBON 1K 5% 1/4W F R430 1-249-437-11 CARBON 47K 5% 1/4W R431 1-247-843-11 CARBON 3.3K 5% 1/4W R432 1-247-883-00 CARBON 150K 5% 1/4W R433 1-249-427-11 CARBON 6.8K 5% 1/4W F R434 1-249-413-11 CARBON 470 5% 1/4W F R438 1-249-441-11 CARBON 100K 5% 1/4W R441 1-249-441-11 CARBON 100K 5% 1/4W R444 1-247-903-00 CARBON 1M 5% 1/4W R464 1-247-903-00 CARBON 1M 5% 1/4W R469 1-247-903-00 CARBON 1M 5% 1/4W R475 1-249-429-11 CARBON 10K 5% 1/4W R476 1-249-439-11 CARBON 68K 5% 1/4W R477 1-249-417-11 CARBON 1K 5% 1/4W F R480 1-249-437-11 CARBON 47K 5% 1/4W R481 1-247-843-11 CARBON 3.3K 5% 1/4W R482 1-247-883-00 CARBON 150K 5% 1/4W R483 1-249-427-11 CARBON 6.8K 5% 1/4W F R484 1-249-413-11 CARBON 470 5% 1/4W F R491 1-249-441-11 CARBON 100K 5% 1/4W R492 1-247-903-00 CARBON 1M 5% 1/4W R494 1-247-903-00 CARBON 1M 5% 1/4W < VARIABLE RESISTOR > RV404 1-225-229-11 RES, VAR, CARBON 100KX4 (MASTER VOLUME) ************************************************************** MISCELLANEOUS ************* 9 1-782-100-11 WIRE (FLAT TYPE) (23 CORE) 13 1-782-074-11 WIRE (FLAT TYPE) (7 CORE) 14 1-782-075-11 WIRE (FLAT TYPE) (9 CORE) !56 1-690-609-21 CORD, POWER FL201 1-517-662-11 INDICATOR TUBE, FLUORESCENT Q603 8-749-010-25 IC MN2488-OPY-M Q604 8-749-010-26 IC MP1620-OPY-M Q653 8-749-010-25 IC MN2488-OPY-M Q654 8-749-010-26 IC MP1620-OPY-M Q703 8-749-010-25 IC MN2488-OPY-M Q704 8-749-010-26 IC MP1620-OPY-M Q753 8-749-010-25 IC MN2488-OPY-M Q754 8-749-010-26 IC MP1620-OPY-M !T901 1-431-258-11 TRANSFORMER, POWER ************************************************************** ACCESSORIES & PACKING MATERIALS ******************************* 1-475-710-11 COMMANDER, STANDARD (RM-U302) 1-501-374-11 ANTENNA, LOOP 1-501-659-41 ANTENNA (FM) 1-501-721-11 ANTENNA (LOOP) 3-862-695-11 MANUAL, INSTRUCTION (ENGLISH) 4-981-643-01 COVER, BATTERY (For RM-U302) ************************************************************** ************** HARDWARE LIST ************** #1 7-682-547-04 SCREW +B 3X6 #2 7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S VOL-TONE www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 46 – STR-V200 Sony Corporation Home A&V Products Company 98D097021-1 Printed in Singapore © 1998. 4 Published by General Engineering Dept. (Shibaura) 9-922-845-11 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com
