SERVICE MANUAL Amplifier section Power Output1) Models of area code CEL, CEK (4 ohms 1 kHz, THD 0.7%) FRONT2): 70 W/ch CENTER2): 70 W SURR2): 70 W/ch (4 ohms 100 Hz, THD 0.7%) SUB WOOFER2): 70 W (4 ohms 1 kHz, THD 10%) FRONT2): 100 W/ch CENTER2): 100 W SURR2): 100 W/ch (4 ohms 100 Hz, THD 10%) SUB WOOFER2): 100 W 1) Measured under the following conditions: 2) Depending on the sound field settings and the source, there may be no sound output. Inputs (Analog) Inputs (Digital) Reproduction frequency range: 28 – 20,000 Hz Tone FM tuner section Tuning range 87.5 - 108.0 MHz Antenna FM wire antenna Antenna terminals 75 ohms, unbalanced Intermediate Frequency 10.7 MHz AM tuner section Tuning range Models of area code CEL, CEK With 9-kHz tuning scale: 531 - 1,602 kHz Antenna Loop antenna Intermediate Frequency 450 kHz General Power requirements Power consumption Power consumption (during standby mode) 0.3 W Dimensions (w/h/d) (Approx.) 430 × 64 × 337 mm including projecting parts and controls Mass (Approx.) 3.3 kg Area code Power requirements CEL, CEK 230 V AC, 50 Hz SA-CD/CD, VIDEO 1, 2 Sensitivity: 1 V Impedance: 50 kiloohms DVD (Coaxial) Sensitivity: – Impedance: 75 ohms VIDEO 2, SA-CD/CD (Optical) Sensitivity: – Impedance: – Gain levels ±6 dB, 1 dB step Area code Power requirements CEL, CEK 230 V AC, 50/60 Hz Area code Power consumption CEL, CEK 110 W Design and specifications are subject to change without notice. FM STEREO/FM-AM RECEIVER AEP Model STR-KS600PM/KS600PW UK Model STR-KS600PM SPECIFICATIONS STR-KS600PM/KS600PW • STR-KS600PM is the receiver section in HT-SF800M. • STR-KS600PW is the receiver section in HTP-32SS. Ver. 1.1 2006.03 9-879-722-02 2006C05-1 © 2006.03 Sony Corporation Home Audio Division Published by Sony Techno Create Corporation This receiver incorporates Dolby* Digital and Pro Logic Surround and the DTS** Digital Surround System. * Manufactured under license from Dolby Laboratories. “Dolby”, “Pro Logic” and the double-D symbol are trademarks of Dolby Laboratories. **“DTS” and “DTS Digital Surround” are registered trademarks of Digital Theater Systems, Inc. – Continued on next page – www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 2 STR-KS600PM/KS600PW TABLE OF CONTENTS 1. SERVICING NOTES ............................................... 3 2. GENERAL ................................................................... 4 3. DISASSEMBLY 3-1. Disassembly Flow ........................................................... 6 3-2. Case ................................................................................. 6 3-3. Front Panel Assy .............................................................. 7 3-4. SMPS Board .................................................................... 7 3-5. LINE FILTER Board ....................................................... 8 3-6. D-AMP Board ................................................................. 8 3-7. DIGITAL Board .............................................................. 9 4. TEST MODE .............................................................. 9 5. DIAGRAMS 5-1. Block Diagram – DSP Section – ..................................... 10 5-2. Block Diagram – AUDIO OUT Section – ....................... 11 5-3. Block Diagram – DISPLAY, POWER SUPPLY Section – ....................... 12 5-4. Printed Wiring Board – DIGITAL Board (Component Side) – .......................... 14 5-5. Printed Wiring Board – DIGITAL Board (Conductor Side) – ............................ 15 5-6. Schematic Diagram – DIGITAL Board (1/3) – ............... 16 5-7. Schematic Diagram – DIGITAL Board (2/3) – ............... 17 5-8. Schematic Diagram – DIGITAL Board (3/3) – ............... 18 5-9. Printed Wiring Board – D-AMP Board (Component Side) – ............................. 20 5-10. Printed Wiring Board – D-AMP Board (Conductor Side) – ............................... 21 5-11. Schematic Diagram – D-AMP Board (1/2) – .................. 22 5-12. Schematic Diagram – D-AMP Board (2/2) – .................. 23 5-13. Printed Wiring Boards – DISPLAY Section –................. 24 5-14. Schematic Diagram – DISPLAY Section – ..................... 25 5-15. Printed Wiring Board – SPEAKER OUT, POWER SUPPLY Section (1/2) – ... 26 5-16. Printed Wiring Boards – SPEAKER OUT, POWER SUPPLY Section (2/2) – ... 27 5-17. Schematic Diagram – SPEAKER OUT, POWER SUPPLY Section – ............ 28 6. EXPLODED VIEWS 6-1. Cover Section .................................................................. 40 6-2. Chassis Block .................................................................. 41 7. ELECTRICAL PARTS LIST ................................ 42 Notes on chip component replacement • Never reuse a disconnected chip component. • Notice that the minus side of a tantalum capacitor may be damaged by heat. SAFETY-RELATED COMPONENT WARNING!! COMPONENTS IDENTIFIED BY MARK 0 OR DOTTED LINE WITH MARK 0 ON THE SCHEMATIC DIAGRAMS AND IN THE PARTS LIST ARE CRITICAL TO SAFE OPERATION. REPLACE THESE COMPONENTS WITH SONY PARTS WHOSE PART NUMBERS APPEAR AS SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUBLISHED BY SONY. About area codes The area code of the receiver you purchased is shown on the lower portion of the rear panel (see the illustration below). Any differences in operation, according to the area code, are clearly indicated in the text, for example, “Models of area code AA only”. FRONT R – + CENTER – + FRONT L – + SURR R + – SUBWOOFER + – SURR L + – 2-XXX-XXX-XX AA Area code www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 3 STR-KS600PM/KS600PW SECTION 1 SERVICING NOTES NOTES ON REPLACEMENT OF THE DIGITAL BOARD New part of EEPROM (IC1131) on the DIGITAL board cannot be used. Therefore, if the mounted DIGITAL board (A-1097-941-A) is replaced, exchange new microcomputer and new EEPROM with that used before the replacement. UNLEADED SOLDER Boards requiring use of unleaded solder are printed with the lead- free mark (LF) indicating the solder contains no lead. (Caution: Some printed circuit boards may not come printed with the lead free mark due to their particular size) : LEAD FREE MARK Unleaded solder has the following characteristics. • Unleaded solder melts at a temperature about 40 °C higher than ordinary solder. Ordinary soldering irons can be used but the iron tip has to be applied to the solder joint for a slightly longer time. Soldering irons using a temperature regulator should be set to about 350 °C. Caution: The printed pattern (copper foil) may peel away if the heated tip is applied for too long, so be careful! • Strong viscosity Unleaded solder is more viscou-s (sticky, less prone to flow) than ordinary solder so use caution not to let solder bridges occur such as on IC pins, etc. • Usable with ordinary solder It is best to use only unleaded solder but unleaded solder may also be added to ordinary solder. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 4 STR-KS600PM/KS600PW SECTION 2 GENERAL This section is extracted from instruction manual. LOCATION OF CONTROLS Main unit Display 2 DVD (indicator) 5 INPUT SELECTOR qd IR (receptor) 8 MASTER VOLUME qg MUTING qf PRESET TUNING + q; PRESET TUNING – 9 SA-CD/CD (indicator) 6 SOUND FIELD qs TUNER (indicator) 7 VIDEO 1 (indicator) 3 VIDEO 2 (indicator) 4 ?/1 (power) 1 ; PLII qa ALPHABETICAL ORDER NUMBERS AND SYMBOLS 1 2 qd qg qs qf qa q; 9 8 7 6 5 4 3 A LFE: Lights up when the disc being played back contains the LFE (Low Frequency Effect) channel and the LFE channel signal is actually being reproduced. B SLEEP: Lights up when sleep timer is activated. C Playback channel indicators: The letters (L, C, R, etc.) indicate the channels being played back. The boxes around the letters vary to show how the receiver downmixes the source sound. L (Front Left), R (Front Right), C (Center (monaural)), SL (Surround Left), SR (Surround Right), S (Surround (monaural or the surround components obtained by Pro Logic processing)) Example: Recording format (Front /Surround): 3/2 Sound Field: A.F.D. AUTO D ; DIGITAL: Lights up when the receiver is decoding signals recorded in the Dolby Digital format. E ; PLII: “; PL” lights up when the receiver applies Pro Logic processing to 2 channel signals in order to output the center and surround channel signals. “; PLII” lights up when the Pro Logic II Movie/Music decoder is activated. Note Dolby Pro Logic and Dolby Pro Logic II decoding do not function for DTS format signals. F D.RANGE: Lights up when dynamic range compression is activated. G Tuner indicators: Lights up when using the receiver to tune in radio stations, etc. H COAX: Lights up when the source signal is a digital signal being input through the COAX terminal. I OPT: Lights up when the source signal is a digital signal being input through the OPT terminal. J DTS: Lights up when DTS signals are input. K SW: Lights up when the audio signal is output from the SUB WOOFER jack. About the indications in the display L C R SL S SR SW STEREO MONO D. RANGE MEMORY DIGITAL SLEEP PL RDS OPT COAX LFE DTS 7 8 qa q; 9 2 1 3 4 5 6 L C R SL SR www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 5 STR-KS600PM/KS600PW * The MASTER VOL +, numeric button 5 and H buttons have a tactile dot. Use the tactile dot as a reference when operating the receiver and other audio/video components. Remote button description 1 2 3 4 6 7 8 0/10 ENTER 9 SYSTEM STANDBY TV/VIDEO SLEEP TEST TONE AV ?/1 VIDEO 1 VIDEO 2 DVD SA-CD/CD 2CH A.F.D. RETURN/EXIT TV CH – PRESET – TV CH + PRESET + TUNING – TV TUNING + REPLAY ADVANCE c STEP C DISPLAY MOVIE MUSIC MEMORY SHIFT D.SKIP CLEAR ANGLE AV MENU TOP MENU/ GUIDE MUTING TV VOL MASTER VOL FM MODE MPX AUDIO D.TUNING ANT JUMP SUBTITLE DUAL MONO TUNER MAIN MENU TV ?/1 ?/1 >10 - F G g f ENTER . H m M X x < < > 5 1 3 2 4 ej ek el eh 8 9 q; qa qs qf qd qj qh qk w; wa* ws wd wf wh wj e; wg wk wl ea *es ef eg ql qg* 5 6 7 ed The tables below show the settings of each button. Remote Button Operations Function A.F.D. ef Receiver Selects the decoding mode for audio sound. ANGLE qs DVD player Selects viewing angle or changes the angles. ANT 0 VCR/ Satellite tuner Selects output signal from the antenna terminal: TV signal or VCR program. AUDIO 9 DVD player/ Satellite tuner Changes the sound to Multiplex or Bilingual or Multi channel TV sound. AV MENU qd VCR/ DVD player/ Satellite tuner Displays menu. AV ?/1 1 VCR/ CD player/ DVD player/ Satellite tuner/ MD deck Turns the audio and video components on or off. CLEAR ea DVD player/ Satellite tuner Clears a mistake when you press the incorrect numeric buttons or returns to continuous playback etc. DISPLAY qh Receiver/ CD player/ VCR/ DVD player/ Satellite tuner/ MD deck Selects information displayed on the TV screen. D.SKIP qa CD player/ DVD player Skips discs (multi-disc changer only). D.TUNING 0 Receiver Enters direct tuning mode. DUAL MONO 8 Receiver Selects the language you want during digital broadcast. DVD 3 Receiver To watch DVD. ENTER qa TV/VCR/ Satellite tuner After selecting a channel, disc or track using the numeric buttons, press to enter the value. Remote Button Operations Function ENTER wl Receiver/ VCR/ DVD player/ Satellite tuner/ CD player/ MD deck Enters the selection. FM MODE 9 Receiver Selects FM monaural or stereo reception. JUMP qs Satellite tuner Toggles between the previous and the current channels. MAIN MENU 5 Receiver Selects the menu of the receiver. MASTER VOL +/– qg Receiver/TV Adjusts the master volume of the receiver. MEMORY qa Receiver Stores the radio stations. MOVIE 6 Receiver Selects the pre- programmed sound fields for movie. MPX 9 VCR Select main or sub language. MUSIC 7 Receiver Selects the pre- programmed sound fields for music. MUTING qf Receiver Mutes the sound from the receiver. PRESET +/– qjwh Receiver Selects preset stations. TV/VCR/ Satellite tuner Select preset channel. RETURN/ EXIT wj DVD player Returns to the previous menu or exits the menu. Satellite tuner Exits the menu. SA-CD/CD 4 Receiver To listen to Super Audio CD or compact disc. SHIFT qs Receiver Selects a memory page for presetting radio stations or tuning to preset stations. Notes • Some functions explained in this section may not work depending on the model. • The above explanation is intended to serve as an example only. Therefore, depending on the component the above operation may not be possible or may operate differently than described. • When you press input buttons (VIDEO 1, VIDEO 2 or DVD), the input mode of the TV might not switch to the corresponding input mode that you want. In this case, press TV/VIDEO button to switch the input mode of the TV. • To activate the buttons with orange printing, press TV and the button you want simultaneously. . Remote Button Operations Function X ws VCR/ CD player/ DVD player/ MD deck/ Tape deck Pauses playback or recording. (Also starts recording with components in recording standby.) x w; VCR/ CD player/ DVD player/ MD deck/ Tape deck Stops playback. O wj DVD player Returns to the previous menu or exits the menu. V/v wk Receiver Selects a menu item. B/b wk Receiver Adjusts or changes the setting. V/v/B/b wk VCR/ Satellite tuner/ DVD player Selects a menu item. Remote Button Operations Function SLEEP el Receiver Activates the sleep function and the duration which the receiver turns off automatically. SUBTITLE 0 DVD player Changes the subtitles. SYSTEM STANDBY (Press AV ?/1 1 and ?/1 2 at the same time) Receiver/ TV/VCR/ CD player/ DVD player/ Satellite tuner/ MD deck Turns off the receiver and other Sony audio/ video components. TEST TONE ek Receiver Outputs test tone. TOP MENU/ GUIDE e; DVD player Displays DVD title. Satellite tuner Display guide menu. TUNER eg Receiver To listen to radio programs. TUNING +/– ql wf Receiver Scans radio station. TV wd TV To watch TV programs. TV CH +/– qj wh TV Selects preset TV channels. TV/VIDEO el TV Selects input signal: TV input or video input. TV VOL +/– qg TV Adjusts the volume of the TV. TV ?/1 2 TV Turns the TV on or off. VIDEO 1 ej Receiver To watch VCR. (VTR mode 3) VIDEO 2 eh Receiver To watch VCR. (VTR mode 1) Remote Button Operations Function 1-9 and 0/10 es Receiver Use with SHIFT to preset radio station or tuning to preset stations and with D.TUNING for direct tuning. CD player/ DVD player/ MD deck Selects track numbers. 0/10 selects track 10. TV/VCR/ Satellite tuner Selects channel numbers. 2CH ed Receiver Selects 2CH STEREO mode. >10 ea VCR/ CD player/ DVD player/ Satellite tuner/ MD deck Selects track numbers over 10. -/-- ea TV Selects the channel entry mode, either one or two digit. ?/1 2 Receiver Turns the receiver on or off. c STEP C REPLAY / ADVANCE wg qk VCR/ DVD player Replay the previous scene or fast forward the current scene. ./> wh qj VCR/ CD player/ DVD player Skips tracks. m/M wf ql DVD player Searches tracks in the forward or backward direction. VCR/ CD player/ MD deck/ Tape deck Fastforwards or rewinds. H wa VCR/ CD player/ DVD player/ MD deck/ Tape deck Starts playback. < < www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com STR-KS600PM/KS600PW 6 Note: Follow the disassembly procedure in the numerical order given. 3-2. CASE • This set can be disassembled in the order shown below. 3-1. DISASSEMBLY FLOW SECTION 3 DISASSEMBLY 3 two tapping screws 1 two screws (BVTP3 × 8) 2 two tapping screws 4 case 3-2. CASE (Page 6) SET 3-3. FRONT PANEL ASSY (Page 7) 3-4. SMPS BOARD (Page 7) 3-5. LINE FILTER BOARD (Page 8) 3-6. D-AMP BOARD (Page 8) 3-7. DIGITAL BOARD (Page 9) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com STR-KS600PM/KS600PW 7 3-3. FRONT PANEL ASSY 3-4. SMPS BOARD 3 seven claws 1 wire (flat type) (17 core) (CNS193) 4 front panel assy 2 four screws (BVTP3 × 8) 1 connector (CNP110) 7 sheet (SMPS) 2 connector (CNP811) 3 connector (CNP900) 4 connector (CNP901) 6 SMPS board 5 four screws (BVTP3 × 6) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com STR-KS600PM/KS600PW 8 3-5. LINE FILTER BOARD 3-6. D-AMP BOARD 0 two 03P insulating bushing qa heatsink assy qs radiation sheet qd four screws (BVTP3 × 6) qf D-AMP board 5 SPK board 2 3 connector (CNP500) 4 connector (CNP510) 1 three screws (BVTP3 × 8) 6 wire (flat type) (25 core) (CNS1101) 7 connector (CNP110) 9 two screws (BVTP3 × 10) 8 connector (CNP900) 1 connector (CNP901) 3 LINE FILTER board 2 two screws (BVTP3 × 6) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 9 9 STR-KS600PM/KS600PW STR-KS600PM/KS600PW 3-7. DIGITAL BOARD 2 three screws (BVTP3 × 8) 6 five screws (BVTP3 × 8) 8 DIGITAL board 7 two screws (BVTP3 × 6) 5 wire (flat type) (17 core) (CNS193) 4 wire (flat type) (25 core) (CNS1101) 1 wire (flat type) (15 core) (CNS195) 3 tuner SECTION 4 TEST MODE FACTORY PRESET MODE All preset contents are reset to the default setting. Procedure: 1. While pressing the PLII and [PRESET TUNING +] buttons, press the I/1 button to turn on the main power. 2. The message “FACTORY” appears and the present contents are reset to the default values. ALL CLEAR MODE All preset contents are cleared when this mode is activated. Use this mode before returning the product to clients upon completion of repair. Procedure: 1. While pressing the PLII and [PRESET TUNING --] buttons, press the I/1 button to turn on the main power. 2. The message “CLEARING !” appears and the memories are reset to the default values. 3. When done, the message “CLEARED” appears. FL CHECK MODE All fluorescent segments are tested. When this test is activated, all segments turn on at the same time, then each segment turns on one after another. Procedure: 1. While pressing the [MUTING] and [PRESET TUNING --] buttons, press the I/1 button to turn on the main power. 2. All segments and all LEDs turn on. 3. Press the [INPUT SELECTOR] button. 4. Half of segments and [VIDEO 1], [SA-CD/CD] LEDs turn on. 5. Press the [INPUT SELECTOR] button once again. 6. Others half of segments and [VIDEO 2], [DVD] LEDs turn on. 7. Press the [INPUT SELECTOR] button once again. 8. All segments and all LEDs turn off. VERSION MODE When this mode is used, the model, the destination and the software version number are displayed. Procedure: 1. While pressing the [SOUND FIELD] and [PRESET TUNING --] buttons, press the I/1 button to turn on the main power. 2. The model, the destination and the software version number appear. KEY CHECK MODE This mode is used to check the key. Procedure: 1. While pressing the [MUTING] and [INPUT SELECTOR] buttons, press the I/1 button to turn on the main power. 2. The message “REST 06” appears. 3. Every pressing of any button other than the I/1 button counts down the buttons. The buttons which are already counted once are not counted again. 4. When all buttons are pressed, the message “REST 00” appears. PROTECTOR AUTO OFF MODE When this mode is used, a protector on state is maintainable. Procedure: 1. While pressing the [MUTING] and PLII buttons, press the I/1 button to turn on the main power. 2. The message “PROT EVER” appears. SOUND FIELD CLEAR MODE The preset sound field is cleared when this mode is activated. Use this mode before returning the product to clients upon completion of repair. Procedure: 1. While pressing the [SOUND FIELD] button, press the I/1 button to turn on the main power. 2. The message “SF. CLR.” appears and initialization is performed. RDS AUTOBETICAL MODE Procedure: 1. While pressing the [INPUT SELECTOR] button, press the I/1 button to turn on the main power. 2. The message “AUTO-BET” appears and scans and stores all the FM and FM RDS stations in the broadcast area. 3. When done, the message “FINISH” appears. w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 10 10 STR-KS600PM/KS600PW STR-KS600PM/KS600PW SECTION 5 DIAGRAMS 5-1. BLOCK DIAGRAM – DSP Section – BOOT SELECT IC1503 LEVEL SHIFT Q1710, 1711 BUFFER IC1600 EEPROM IC1131 SYSTEM CONTROLLER IC1601 (1/3) OPTICAL RECEIVER IC1700 D1103 CS 6 10 A 9 B X2 15 X0 12 X1 L CH R CH DO/ST DI 14 X3 11 LIN 1 SDI2 30 BCKI2 29 LRCKI2 28 KFSIO 22 SDI1 18 BCKI1 17 AUDIO 69 LRCKI1 15 DIN0 3 D0 98 D1 97 CLK 95 CE 96 ERROR 99 ANA/DIG 24 18 19 20 4 5 2 7 6 9 XMODE 93 XSTATE 100 DATA0 1 AD_RST 10 SELECT_B 21 SELECT_A 22 88 EXLOCK 59 RSTB 6 CS0 44 SDO1 23 SDO2 24 SDO3 25 SCKOUT 14 BCKO 20 LRCKO DATA1 DATA1 – DATA3, SCK, BCK, LRCK DATA2 DATA3 SCK BCK LRCK 19 GP10 67 DOUT 15 SYSCLK 16 BCK 14 LRCK 13 X 13 DO 35 DI 36 CLK 38 CKE 37 ERROR 34 XMODE 48 XSTATE DIR DO HDOUT 35 HDIN 33 HCLK 34 HCS 36 HACN 32 DECODE 68 PM 113 XRST 2 GP12 37 DIR DATA0 DIR DI DIR CLK DIR CE DIR ERROR DIR XMODE DIR XSTATE DIR DO DIR DATA0 DIR DI DIR CLK DIR CE DIR ERROR DIR XMODE DIR XSTATE 17 XMCLK 20 DATAO 16 BLK 14 LRCK 15 CKOUT 13 AUDIO 24 OPT IN SA-CD/CD OPTICAL RECEIVER IC1701 DIN1 4 OPT IN VIDEO 2 SCHMITT TRIGGER IC1702 DIGITAL AUDIO INTERFACE RECEIVER IC1301 DIGITAL AUDIO SIGNAL PROCESSOR IC1501 DIN2 J1700 5 COAX IN DVD FM 75Ω COAXIAL 86 85 87 89 53 52 43 66 65 WE 17 WE0 45 BST 56 DIGITAL SA-CD/CD VIDEO 2 AUDIO IN J1710 FM/AM TUNER PACK TN1 VIDEO 1 AM L R L R L R R-CH R-CH R-CH ANALOG AUDIO INPUT SELECT IC1710 A/D CONVERTER IC1602 S-RAM IC1502 R-CH 21 22 X1301 12.288MHz XOUT XIN 9 12 X1502 13.9MHz MCLK1 MCLK2 FM ANT GND AM ANT GND CLOCK CE MUTE TUNED STEREO RDS DATA RDS_CL FM SIG OUT T_DO T. DATA T. CLK SLATCH T_MUTE TUNED STEREO RDS DATA RDS CLK RDS SIGNAL 108, 107, 105 – 102, 99, 98, 80 – 77, 75 – 72 7 – 10, 13 – 16, 29 – 32, 35 – 38 112, 110, 109, 97 – 92, 82 – 85, 66 – 64 D0 – D15 A0 – A15 5 – 1, 44 – 42, 27 – 24, 21 – 18 D0 – D15 A0 – A15 D1301 HDOUT HDIN HCLK HCS HACN GP9 PM XRST GP12 92 LRCK_SW 3 BST 82 83 X0 X1 34 SDA 33 SCL X1101 24MHz A • SIGNAL PATH : TUNER : ANALOG INPUT : DIGITAL INPUT • R-ch is omitted due to same as L-ch. (Page 11) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 11 11 STR-KS600PM/KS600PW STR-KS600PM/KS600PW 5-2. BLOCK DIAGRAM – AUDIO OUT Section – • SIGNAL PATH : AUDIO /RST /SD 4 13 DIGITAL POWER AMP IC102 2 PWM_BP TM500 (+) (–) 29 OUT_B 25 OUT_A 30 OUT_B 26 OUT_A STREAM PROCESSOR IC108 31 DATA 36 XFSIIN 30 BCK 23 SCLATCH 27 INIT 19 SOFTMUTE 21 SCDT 29 LRCK 22 SCSHIFT LATCH1 INIT SOFTMUTE SCDT SHIFT 6 OUTR1 11 OUTL1 4 OUTR2 17 PWM_AP 9 OUTL2 38 FSOI OVER LOAD DETECT Q103, 104 LOW-PASS FILTER FRONT L FRONT R SYSTEM CONTROLLER IC1601 (2/3) 37 FSOCKO 48 XFSOIN 14 XFSOUT SURR L SURR R CENTER SPEAKERS SUBWOOFER DATA1 SCK BCK LRCK INIT LATCH1 LATCH2 LATCH3 SCDT SHIFT BUFFER IC305 DATA1 – DATA3, SCK, BCK, LRCKO A X450 49.152MHz 62 SCDT 61 SHIFT 60 LAT1 59 LAT2 58 LAT3 64 INT SOFTMUTE 63 SOFT_MUTE OVF 68 OVF OVFW 78 OVFW 32 POWER_RST 26 POWER_SD 25 OVF FLAGL OVF 24 OVF FLAGR STREAM PROCESSOR IC109 31 DATA 36 XFSIIN 30 BCK 23 SCLATCH 27 INIT 19 SOFTMUTE 21 SCDT 29 LRCK 22 SCSHIFT LATCH1 INIT SOFTMUTE SCDT SHIFT 6 OUTR1 11 OUTL1 4 OUTR2 9 OUTL2 38 FSOI 48 XFSOIN 14 XFSOUT DATA2 SCK BCK LRCK 25 OVF FLAGL OVF 24 OVF FLAGR STREAM PROCESSOR IC110 31 DATA 36 XFSIIN 30 BCK 23 SCLATCH 27 INIT 19 SOFTMUTE 21 SCDT 29 LRCK 22 SCSHIFT LATCH1 INIT SOFTMUTE SCDT SHIFT 6 OUTR1 11 OUTL1 4 OUTR2 9 OUTL2 38 FSOI 48 XFSOIN DATA3 SCK BCK LRCK 25 OVF FLAGL OVF 24 OVF FLAGR OVFW /RST /SD 4 13 DIGITAL POWER AMP IC101 2 PWM_BP (+) (–) 29 OUT_B 25 OUT_A 30 OUT_B 26 OUT_A 17 PWM_AP OVER LOAD DETECT Q101, 102 LOW-PASS FILTER /RST /SD 4 13 DIGITAL POWER AMP IC104 2 PWM_BP (+) (–) 29 OUT_B 25 OUT_A 30 OUT_B 26 OUT_A 17 PWM_AP OVER LOAD DETECT Q105, 106 LOW-PASS FILTER /RST /SD 4 13 DIGITAL POWER AMP IC103 2 PWM_BP (+) (–) 29 OUT_B 25 OUT_A 30 OUT_B 26 OUT_A 17 PWM_AP OVER LOAD DETECT Q107, 108 LOW-PASS FILTER /RST /SD 4 13 DIGITAL POWER AMP IC105 2 PWM_BP (+) (–) 29 OUT_B 25 OUT_A 30 OUT_B 26 OUT_A 17 PWM_AP OVER LOAD DETECT Q109, 110 LOW-PASS FILTER /RST /SD 4 13 DIGITAL POWER AMP IC106 2 PWM_BP (+) (–) 29 OUT_B 25 OUT_A 30 OUT_B 26 OUT_A 17 PWM_AP OVER LOAD DETECT Q111, 112 LOW-PASS FILTER PROTECT DETCT Q301 (Page 10) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 12 12 STR-KS600PM/KS600PW STR-KS600PM/KS600PW 5-3. BLOCK DIAGRAM – DISPLAY, POWER SUPPLY Section – 3 SWITCHING REGULATOR IC910 DRAIN (AC IN) MAIN POWER TRANSFORMER T910 SUB POWER TRANSFORMER T920 F901 VCC D917 RECT D902, 903 ISOLATOR PC801 OSC Q801, 802 B+ SWITCH Q910 BUFFER IC802 4 VCC 1 OCP 5 FB/OLP 8 SWITCHING REGULATOR IC930 DRAIN 2 VCC 4 OCP/FB 5 START RECT D801 RECT D830 ISOLATOR PC803 ISOLATOR PC802 SWITCHING IC801 D932 D935 D831 D1006 STBY +4V D930 +20V REGULATOR Q911 OVER CURRENT DETECT Q930 OVER CURRENT DETECT Q931 AC OFF DETECT Q821, 822 POWER ON/OFF CONTROL Q820 +6V REGULATOR Q803 +31V STBY +3.3V +4V REGULATOR IC822 RESET SIGNAL GENERATOR IC1111 48 STOP P. STOP 77 RSTX 8 PWM_DA 46 P. CONT1 55 FUSE DETECT SYSTEM CONTROLLER IC1601 (3/3) RECT D901 + D934 D919, 920 TH901 +12V +12V REGULATOR IC821 +7V REGULATOR IC1025 +3.3V +3.3V REGULATOR IC820 ADC +5V +5V REGULATOR IC1035 +2.6V +2.6V REGULATOR IC1034 +5V +5V REGULATOR IC1031 RDS +3.3V +3.3V REGULATOR IC1711 +1.8V +1.8V REGULATOR IC303 +9V +9V REGULATOR IC1712 FL FL VEE FOR FLUORESCENT INDICATOR TUBE DC/DC CONVERTER T700 RECT D700 – 703 OSC Q700, 701 72 FL_DATA 73 FL_CLK 74 FL_STB FLUORESCENT INDICATOR TUBE DRIVER, LED DRIVER IC700 7 DIN 8 CLK 9 STB 1 DVD LED 2 SA-CD/CD LED 3 VIDEO2 LED 4 VIDEO1 LED D705 – 708 (PANEL INDICATOR) FLUORESCENT INDICATOR TUBE FL700 SEG1 – SEG16 14 – 29 GRID1 – GRID12 42 – 31 54 SIRCS ROTARY ENCODER RV700 LEVEL SHIFT IC1651 REMOTE CONTROL RECEIVER IC701 VOLUME 38 – 40 A/D0 – A/D2 S701 – 705 56 POWER_KEY 70 VOLB 71 VOLA 67 TUNER_LED D710 LED DRIVE Q710 TUNER S706 (POWER) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 13 13 STR-KS600PM/KS600PW STR-KS600PM/KS600PW • Note for Printed Wiring Boards and Schematic Diagrams Note on Printed Wiring Board: • X : parts extracted from the component side. • Y : parts extracted from the conductor side. • x : parts mounted on the conductor side. • f : internal component. • : Pattern from the side which enables seeing. (The other layers' patterns are not indicated.) • Indication of transistor Caution: Pattern face side: Parts on the pattern face side seen from (Conductor Side) the pattern face are indicated. Parts face side: Parts on the parts face side seen from (Component Side) the parts face are indicated. Note on Schematic Diagram: • All capacitors are in µF unless otherwise noted. (p: pF) 50 WV or less are not indicated except for electrolytics and tantalums. • All resistors are in Ω and 1/4 W or less unless otherwise specified. • f : internal component. • 2 : nonflammable resistor. • 5 : fusible resistor. • C : panel designation. • A : B+ Line. • B : B– Line. • Voltages and waveforms are dc with respect to ground under no-signal (detuned) conditions. no mark : TUNER • Voltages are taken with a VOM (Input impedance 10 MΩ). Voltage variations may be noted due to normal produc- tion tolerances. • Waveforms are taken with a oscilloscope. Voltage variations may be noted due to normal produc- tion tolerances. • Circled numbers refer to waveforms. • Signal path. J : DIGITAL INPUT F : ANALOG INPUT f : TUNER Note: The components identified by mark 0 or dotted line with mark 0 are critical for safety. Replace only with part number specified. C B These are omitted. E Q B These are omitted. C E Q • Circuit Boards Location DIGITAL board VOLUME board DISPLAY board SMPS board LINE FILTER board D-AMP board SPK board w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 14 14 STR-KS600PM/KS600PW STR-KS600PM/KS600PW R1120 X1101 R1166 IC1301 IC1502 IC1501 IC1601 R1089 IC1651 R1362 C1301 C1302 R1301 R1302 R1303 R1304 C1303 C1304 C1305 R1606 R1074 L1604 R1076 X1301 R1087 R1523 R1515 C1521 C1522 R1261 R1502 R1503 R1504 R1505 R1506 FB1503 R1073 R1151 R1305 R1311 R1360 R1306 R1307 R1178 R1170 R1171 R1172 R1173 R1174 R1190 R1183 R1159 R1124 R1129 R1105 R1186 R1122 R1123 R1119 R1126 R1125 R1180 R1053 R1056 R1529 R1308 R1309 D1301 R1312 R1313 R1315 R1316 R1136 R1137 R1134 R1135 R1041 R1140 R1142 R1143 R1144 IC1503 IC1034 R1160 R1161 R1162 R1121 R1150 R1501 R1149 IC1131 R1158 R1071 R1072 R1508 R1509 R1511 R1078 C1299 R1541 R1555 R1168 R1548 R1549 R1550 R1551 R1552 R1553 R1554 R1525 R1526 R1518 R1519 R1520 R1521 R1522 R1517 R1547 R1532 R1533 R1534 R1535 R1536 R1537 R1538 R1539 R1540 R1542 R1543 R1544 R1527 R1528 R1184 FB1305 IC1111 IC1602 R1127 R1189 C1107 C1137 R1128 R1604 R1260 FB1102 FB1302 FB1312 D1103 R1185 R1187 FB1502 R1188 R1167 FB1101 R1182 R1181 R1192 R1191 R1195 R1058 R1059 R1169 R1113 R1070 R1115 FB1501 C1033 IC1600 C1603 R1251 C1108 R1079 C1602 R1653 C1601 R1652 C1652 R1654 R1602 C1651 R1603 R1201 R1651 C1441 R1601 R1179 R1607 C1443 FB1511 R1044 C1483 FB1301 R1088 R1252 FB1308 R1175 R1608 X1502 IC1702 D1700 JR1101 JR1102 FB1700 FB1701 Q1710 Q1711 C1700 C1701 C1707 C1708 C1723 R1700 R1701 R1702 R1703 R1704 R1705 R1706 R1707 R1728 R1729 R1730 R1731 R1732 R1733 FB1702 FB1703 FB1704 FB1705 R1708 R1709 R1710 R1711 IC1710 D1001 L1600 C1705 31 30 1 30 1 1 12 36 37 48 24 13 25 61 90 91 120 60 31 51 80 50 100 81 1-864-851- 11 (11) DIGITAL BOARD (COMPONENT SIDE) E E 1 3 5 4 1 3 2 A B C D E F G 1 2 3 4 5 5-4. PRINTED WIRING BOARD – DIGITAL Board (Component Side) – • See page 13 for Circuit Boards Location. : Uses unleaded solder. D1001 G-1 D1103 F-3 D1301 D-5 D1700 B-4 IC1034 G-3 IC1111 D-2 IC1131 D-2 IC1301 D-5 IC1501 E-4 IC1502 E-5 IC1503 F-3 IC1600 C-4 IC1601 G-2 IC1602 D-4 IC1651 F-1 IC1702 B-4 IC1710 B-2 Q1710 C-3 Q1711 C-3 • Semiconductor Location Ref. No. Location w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 15 15 STR-KS600PM/KS600PW STR-KS600PM/KS600PW 5-5. PRINTED WIRING BOARD – DIGITAL Board (Conductor Side) – • See page 13 for Circuit Boards Location. : Uses unleaded solder. CNS195 CNS193 C1306 C1069 CNS192 C1525 C1515 C1032 C1656 IC1025 IC1035 C1036 C1024 C1026 C1035 C1936 C1605 C1655 C1610 C1653 C1604 C1654 CNP110 G1000 CNS1101 C1330 IC1031 IC1700 IC1701 IC1711 IC1712 J1700 J1710 C1702 C1703 C1706 C1716 C1721 C1724 C1725 C1726 C1727 C1728 C1730 C1732 C1717 C1718 C1715 C1720 C1719 C1517 C1504 R1091 R1092 C1607 C1138 C1502 R1049 C1505 R1096 R1097 R1086 R1082 R1085 R1083 R1570 R1081 C1142 C1121 C1122 R1193 C1123 C1124 C1125 C1105 R1636 C1104 R1546 R1545 R1556 C1620 R1635 C1657 R1314 C1310 C1309 C1308 C1312 C1313 C1314 C1315 R1317 R1318 C1609 C1067 C1031 R1513 R1571 R1572 R1573 R1574 C1508 C1507 C1506 C1503 C1501 C1509 C1510 R1514 C1511 R1512 C1513 C1514 C1519 C1520 C1516 C1518 C1066 C1100 C1068 C1025 C1034 R1163 C1163 C1252 C1102 C1129 C1130 R1054 R1055 C1065 C1251 R1610 C1659 C1404 R1043 R1605 D1003 FB1313 D1004 R1165 C1139 D1006 R1310 C1331 L1603 JR1010 JR1011 JR1104 C1704 C1709 C1710 C1722 C1729 C1731 R1715 R1716 R1721 R1722 R1724 R1725 R1726 R1727 C1711 C1712 C1713 C1714 R1717 R1723 R1713 R1720 R1719 R1714 R1712 R1718 JR1106 1 3 DIGITAL BOARD (CONDUCTOR SIDE) 2 1 24 25 1-864-851- 11 (11) (CHASSIS) TN1 FM/AM TUNER PACK SUPPLIED WITH THE ASSEMBLED BLOCK FM 75Ω COAXIAL ANTENNA AM DISPLAY BOARD CNS703 C SMPS BOARD CN820 B D-AMP BOARD CNS301 A NC 1 3 1 1 11 3 VIDEO 1 AUDIO IN L R VIDEO 2 L R SA-CD/CD COAX IN DVD OPT IN VIDEO 2 OPT IN SA-CD/CD L R DIGITAL 1 3 1 3 1 3 1 3 A B C D E F G 1 2 3 4 5 6 D1003 D-2 D1004 D-2 D1006 G-5 IC1025 G-4 IC1031 G-4 IC1035 E-4 IC1700 A-2 IC1701 A-3 IC1711 D-4 IC1712 D-4 • Semiconductor Location Ref. No. Location (Page 21) (Page 24) (Page 27) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 16 16 STR-KS600PM/KS600PW STR-KS600PM/KS600PW R1307 R1309 R1312 R1313 R1315 R1306 R1606 R1607 R1651 C1601 R1705 R1712 R1713 R1714 R1715 R1716 R1717 R1718 R1719 R1720 R1721 R1722 R1723 C1725 R1729 FB1511 FB1313 FB1305 C1700 C1701 C1703 R1702 R1703 C1705 IC1702 C1708 R1704 C1707 C1706 C1702 D1700 FB1308 R1362 R1700 C1301 C1305 C1306 R1301 R1302 R1304 C1304 C1303 R1303 C1302 R1314 C1331 C1330 C1308 R1360 C1309 C1310 FB1301 R1308 D1301 R1305 C1603 C1609 R1605 C1604 C1653 C1659 R1603 C1656 C1654 R1653 IC1602 C1655 C1607 C1657 C1651 R1602 R1604 R1601 C1035 R1610 C1034 IC1600 R1311 FB1302 C1704 R1706 R1707 R1708 R1709 R1710 R1711 FB1705 FB1704 FB1703 FB1702 FB1701 FB1700 C1715 C1720 C1719 C1718 C1717 C1716 Q1711 C1252 R1261 R1260 C1732 C1731 IC1711 C1728 C1729 FB1312 C1251 C1441 R1727 D1003 D1004 CNS195 R1251 R1252 C1730 IC1301 R1701 R1652 R1654 C1652 C1605 C1602 C1724 R1310 X1301 C1315 R1318 R1317 R1316 C1313 C1312 C1314 C1404 C1610 R1608 C1443 C1483 R1151 R1731 R1733 C1727 Q1710 R1728 R1732 R1730 R1726 C1726 C1723 R1725 C1721 R1724 C1722 C1709 C1710 C1711 C1712 C1713 C1714 IC1712 JR1101 JR1102 IC1035 IC1710 J1710 IC1700 IC1701 J1700 100 100 100 100 100 22 100 1k 10k 220p 100 10k 10k 10k 10k 10k 10k 10k 10k 10k 10k 10k 10k 10 50V 100 0.1 0.1 22 50V 1k 22k 1p TC7WU04F 47p 560k 0.1 1000 6.3V 10 50V 1SS355TE-17 100 100 0.1 0.1 47 16V 5.6k 4.7k 100 0.01 0.1 33k 0.01 10k 0.1 10 50V 0.1 100 18p 18p 100 1SS355TE-17 470 0.1 0.1 4.7k L1603 10µH 100 16V 10 50V 0.1 3.3k 47 50V 47 50V 3.3k PCM1800 10 50V 0.1 0.1 220p 470 1k 10k 470 10V 4.7k 0.1 NJM4565M(TE2) 100 0.1 1k 1k 1k 1k 1k 1k 10 50V 10 50V 10 50V 10 50V 10 50V 10 50V DTC124EKA-T146 0.1 0 0 47 16V 0.1 TA78033LS 47 16V 0.1 0.1 0.0033 10k ISS367-T3 ISS367-T3 15P 39k 39k 10 50V LC89056W 75 10k 10k 220p 10 50V 220p 100 16V 1M 12.288MHz 0.1 10k 10k 100 100p 0.1 0.1 0.1 L1604 10µH 47 16V 2.2k 470p 470p 100 10k 10k 10 50V DTC124EKA- T146 100 10k 10k 10k 100 16V 0.1 10k 100 16V 10k 0.1 100p 100p 100p 100p 100p 100p TA7809 0 0 TA7805LS MC14052 BDR2 TORX141 TORX141 A1 A2 A3 A4 A5 A6 A8 A9 A10 A12 B1 B2 B8 B3 B4 B5 B6 B7 A13 A11 DATAO XSTATE CE DI DO CLK XMODE T_MUTE LAT TDA TDO TCLK RDS DATA RDS_CL FM SIG OUT RDS(3.3V) MUTE R CH GND L CH TUNED VDD 10V CE DI DO/ST CLOCK STEREO +3.3V REGULATOR +9V REGULATOR O I G O I G A/D CONVERTER DIGITAL AUDIO INTERFACE RECEIVER BUFFER G V O I G +5V REGULATOR V G SCHMITT TRIGGER ANALOG AUDIO INPUT SELECT LEVEL SHIFT LEVEL SHIFT (CHASSIS) L R L R L R SA-CD/CD VIDEO 2 VIDEO 1 AUDIO IN (CHASSIS) COAX IN DVD (1/3) OPTICAL RECEIVER OPTICAL RECEIVER OPT IN SA-CD/CD OPT IN VIDEO 2 DIGITAL AM COAXIAL FM 75Ω THE ASSEMBLED BLOCK SUPPLIED WITH FM/AM TUNER PACK TN1 • See page 19 for Waveforms. • See page 29 for IC Block Diagrams. • See page 34 for IC Pin Function Description. 5-6. SCHEMATIC DIAGRAM – DIGITAL Board (1/3) – (Page 18) (Page 17) (Page 18) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 17 17 STR-KS600PM/KS600PW STR-KS600PM/KS600PW • See page 19 for Waveforms. • See page 29 for IC Block Diagrams. • See page 34 for IC Pin Function Description. 5-7. SCHEMATIC DIAGRAM – DIGITAL Board (2/3) – R1532 R1533 R1545 R1546 R1548 R1549 R1550 R1551 R1502 R1191 R1192 R1195 R1181 R1182 R1183 R1184 R1185 R1187 R1188 R1171 R1172 R1173 R1170 R1166 R1174 JR1106 C1507 R1520 R1521 R1522 R1518 R1519 R1517 R1554 R1553 R1552 R1525 R1526 C1519 R1534 R1547 R1541 R1535 R1536 R1537 R1538 R1539 R1540 R1542 R1543 R1555 R1544 R1527 R1528 R1514 C1510 C1514 C1506 R1570 R1571 R1572 R1573 R1574 R1508 R1161 R1160 R1509 R1121 C1504 C1505 R1506 R1505 R1504 R1503 R1523 R1513 C1522 X1502 R1515 C1521 R1501 C1511 C1501 R1512 R1511 R1142 C1520 FB1501 FB1502 C1516 C1515 C1502 C1518 C1525 C1517 C1509 R1150 C1503 FB1503 R1556 CNS1101 IC1502 IC1503 R1120 R1529 C1508 C1513 JR1104 IC1501 220 220 220 220 220 220 220 220 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 0 0.1 220 220 220 220 220 220 220 220 220 220 220 0.1 220 220 220 220 220 220 220 220 220 220 220 220 220 220 220 10k 0.1 0.1 0.1 10k 10k 10k 10k 10k 100 100 100 100 100 0.1 0.1 100 100 100 220 220 10k 10p 13.9MHz 1M 10p 100 0.1 0.1 1k 100 100 0.1 0.1 470 10V 0.1 0.1 100 16V 470 10V 0.1 100 0.1 100 25P IS61LV6416-10TLT TC7WH157FU 100 220 0.1 0.1 0 CXD9720BQ B8 B1 B2 B3 B4 B5 B6 B7 C1 C2 C3 C4 C5 C6 C7 C8 C9 INT SMUTE SCDT SHIFT HDOUT GP12 PM XRST HACN HCS BST GP9 A7 A8 A13 A14 A15 A7 A8 A9 A10 A11 A12 A13 A14 A15 D8 D9 D10 D11 D12 D13 D14 D15 A10 A11 A12 A9 D8 D9 D10 D11 D12 D13 D14 D15 A0 A0 A1 A1 A2 A2 D0 D0 D1 D1 D2 D2 D3 D3 D4 D4 D5 D5 D6 D6 D7 D7 A3 A3 A4 A4 A5 A5 A6 CS0 CS0 WE0 WE0 A6 LAT1 LAT2 LAT3 OVFW OVF FON FCTL FCLK HCLK HDIN D1 D2 D3 BCKO LRCKO DGND SCDT SHIFT DGND LAT1 LAT2 LAT3 INIT REST SD DGND SOFT MUTE OVF SCK FAN-CLK FAN ON/OFF FAN-CTRL DGND OVFW DGND (2/3) S-RAM DIGITAL AUDIO SIGNAL PROCESSOR BOOT SELECT (Page 16) (Page 23) (Page 18) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 18 18 STR-KS600PM/KS600PW STR-KS600PM/KS600PW R1201 R1122 R1124 R1167 R1168 R1119 R1125 R1126 R1081 R1082 R1086 R1087 R1076 R1092 R1091 R1096 R1115 R1113 R1078 R1079 R1089 R1074 R1053 FB1102 C1123 C1124 C1031 R1137 R1070 R1083 R1193 C1125 C1121 R1165 C1104 C1620 R1071 C1142 R1072 R1085 R1169 R1123 R1055 R1056 R1054 R1636 C1105 C1100 C1102 C1122 IC1131 R1128 C1065 C1066 C1138 R1189 R1043 R1136 R1135 R1134 R1140 R1041 R1149 R1144 R1143 R1044 FB1101 R1179 R1088 R1180 C1067 C1025 R1190 C1033 C1936 C1036 C1032 R1163 C1024 IC1025 C1026 C1108 C1137 D1006 D1001 CNP110 R1049 R1097 C1069 R1158 R1159 C1163 R1073 CNS192 CNS193 C1068 R1635 R1186 R1105 R1129 R1175 R1059 R1058 C1130 C1129 C1107 C1299 R1178 D1103 R1162 C1139 IC1034 IC1031 IC1111 X1101 IC1601 G1000 IC1651 R1127 22k 100 100 100 100 1k 1k 1k 10k 10k 10k 100 100 10k 10k 10k 100 100 10k 10k 10k 10k 100 0.1 0.1 0.1 100 10k 10k 0 0.1 0.1 0 0.1 0.1 10k 0.1 10k 10k 100 100 10k 10k 10k 2.2k 0.1 0.1 0.1 0.1 BR24L16F-WE2 100 220p 220p 0.1 10k 10k 100 100 100 100 100 100 100 100 100 10k 10k 10k 220p 0.1 10k 0.1 47 50V 10 50V 470 10V 4.7k 10 50V TA7807 47 16V 0.1 0.01 1SS355TE-17 EC10QS04 11P 10k 100k 10 50V 3.3k 3.3k 0.1 10k 7P 17P L1600 10µH 0.1 2.2k 10k 10k 100 100 220 220 0.01 0.01 0.1 0.1 10k 1SS355TE-17 100 0.1 NLM2391DL1-26 TA7805LS S-80929CNMC 24MHz MB90488BPF-G -111E1 TC74VHCT08AFT 100 A1 A2 A3 A4 A5 A6 A8 A9 A10 A11 A12 A13 C1 C2 C3 C4 C5 C7 C6 C8 C9 LAT3 LAT2 LAT1 SHIFT SCDT SMUTE INT FCLK FON FCTL OVF TDA TCLK OVFW HCLK HDIN HDOUT GP12 PM XRST HACN HCS BST GP9 MD2 MD2 MD0 MD0 DIN DIN CLK CLK STB STB DATAO DO DI CE CLK XMODE XSTATE LAT TDO T_MUTE VOL_JOG(2A) VOL_JOG(2B) FL_LAT FL_DIN FL_CLK GND +3.3V(STBY) AD2 AD1 AD0 +5V GND P_CONT1 STOP STBY_4V GND GND GND GND GND POWER SW SIRCS GND PWM-DA +6.5V TUNER_LED FLASH1 FLASH2 VDD GND RESET MD0 MD2 DATAO GP9 BST HCS HACN XRST PM VSS HDOUT HDIN HCLK VCC5 ANA/DIG AVCC AVRH AVSS A/D0 A/D1 A/D2 VSS VERSION MD0 MD1 MD2 SIRCS POWER KEY TUNED RSTX X1A X0A VSS X0 X1 VCC3 XMODE CLK CE ERROR XSTATE CKSEL1 MODEL FUSE DETECT SDA SCL WOOFER RELAY FAN_ON FAN_CLK FLASH1 RDS DATA RDS CLK RDS SIGNAL XSCEN XRST GP12 AD_RST 157_CTL1 157_CTL2 14052_CTL1 POWER_SD NC POWER_RST P.CONT1 LAT3 LAT2 LAT1 SHIFT SCDT SOFT_MUTE INT VOLA VOLB FL_CLK FL_STB SLATCH T_DO VIDEO-SW1 VIDEO-SW2 VIDEO-MUTE LRCK_SW TC74AC_A TC74AC_B NO USE FAN_CTL OVF PWM_DA T.CLK T.DATA A/D3 FLASH2 T_MUTE SELECT_A SELECT_B TUNER_LED (3/3) +2.6V REGULATOR +5V REGULATOR I O G I O G I O G +7V REGULATOR RESET SIGNAL GENARATOR O V G NC CD STEREO D1 D0 SYSTEM CONTROLLER EEPROM +12V (CHASSIS) LEVEL SHIFT V G +3.3V NC SMPS RST STOP P.STOP FL_DATA OVFW • See page 19 for Waveforms. • See page 29 for IC Block Diagrams. • See page 34 for IC Pin Function Description. 5-8. SCHEMATIC DIAGRAM – DIGITAL Board (3/3) – (Page 17) (Page 16) (Page 28) (Page 25) (Page 16) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 19 19 STR-KS600PM/KS600PW STR-KS600PM/KS600PW • Waveforms – D-AMP Board – – DIGITAL Board – – DISPLAY Board – 1 IC1301 qd (CKOUT) 1 V/DIV, 50 ns/DIV 81.5 ns 3.8Vp-p 2 IC1301 qf (BCK) 1 V/DIV, 100 ns/DIV 326 ns 3.7Vp-p 20.8 µs 3.6 Vp-p 3 IC1301 qg (LRCK) 1 V/DIV, 10 µs/DIV 4 IC1301 w; (XMCK) 1 V/DIV, 50 ns/DIV 81 ns 3.8 Vp-p 5 IC1301 wa (XOUT) 1 V/DIV, 50 ns/DIV 81 ns 3.9 Vp-p 6 IC1501 qs (MCLK2) 1 V/DIV, 20 ns/DIV 71.8 ns 3.6 Vp-p 7 IC1501 qf (SCKOUT) 1 V/DIV, 50 ns/DIV 81 ns 3.8 Vp-p 20.8 µs 3.5 Vp-p 8 IC1501 ql (LRCKO) 1 V/DIV, 10 µs/DIV 9 IC1501 w; (BCKO) 1 V/DIV, 100 ns/DIV 326 ns 3.7 Vp-p q; IC1601 id (X1) 1 V/DIV, 20 ns/DIV 41.4 ns 3 Vp-p qs IC108 qf (XFSOOUT) 1 V/DIV, 10 ns/DIV 20.5 ns 3.4 Vp-p 20.6 µs 3.9 Vp-p qd IC108 ej (FSOCKO) 1 V/DIV, 10 µs/DIV qa IC109 qf (XFSOOUT) 1 V/DIV, 10 ns/DIV 20.5 ns 3.5 Vp-p qf IC305 4 2 V/DIV, 10 ns/DIV 20.5 µs 4 Vp-p wa IC700 5 (OSC) 1 V/DIV, 1 µs/DIV 2.4 µs 2.2 Vp-p ws Q700, 701 (Collector) 5 V/DIV, 5 µs/DIV 13.1 µs 20.8 Vp-p w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 20 20 STR-KS600PM/KS600PW STR-KS600PM/KS600PW 5-9. PRINTED WIRING BOARD – D-AMP Board (Component Side) – • See page 13 for Circuit Boards Location. : Uses unleaded solder. C178 R119 Q110 C161 R196 C208 R206 C385 IC102 C201 C271 R205 C176 C175 C166 R191 IC106 C272 R195 R204 C209 C165 R395 C188 IC105 C207 R400 C206 R194 R203 C210 C174 C164 IC104 Q112 Q108 C163 C202 C205 Q106 C394 Q102 R193 R202 C393 C173 C391 C204 IC303 Q104 IC103 Q301 C203 C371 C171 C392 R192 R201 C172 C162 C327 IC110 R319 R326 R328 C328 R383 R317 R316 C318 IC109 R327 R324 C319 R375 R376 R377 R378 R318 C395 C199 R122 R311 C146 C200 R121 R123 C145 C143 C190 C144 C198 C309 X450 IC305 R381 R382 IC108 R329 R322 R323 R321 R325 R345 C310 R347 C142 C189 R371 R372 R373 R374 R384 R320 R310 R314 R346 R348 C141 IC101 C168 C159 C150 C140 C139 R110 R109 R113 R114 R116 R124 C396 R344 D-AMP BOARD (COMPONENT SIDE) 1 36 25 12 13 24 48 37 1 36 25 12 13 24 48 37 1 1 3 4 5 36 25 12 13 24 48 37 1-864-846- 11 (11) E E E E E E E 1 3 5 4 A B C D E 1 2 3 4 5 6 7 F IC101 D-5 IC102 D-5 IC103 D-4 IC104 D-3 IC105 D-3 IC106 D-2 IC108 E-6 IC109 E-5 IC110 E-3 IC303 D-6 IC305 E-6 Q102 A-6 Q104 A-6 Q106 A-3 Q108 A-3 Q110 A-3 Q112 A-3 Q301 B-7 • Semiconductor Location Ref. No. Location w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 21 21 STR-KS600PM/KS600PW STR-KS600PM/KS600PW 5-10. PRINTED WIRING BOARD – D-AMP Board (Conductor Side) – • See page 13 for Circuit Boards Location. : Uses unleaded solder. CN303 CN305 CNS301 C375 C373 C211 C191 C355 L101 C216 C196 L136 L116 L126 C226 L106 C215 C195 L135 L115 L125 C225 L105 C214 C221 C194 L134 C158 EP102 L114 L124 C224 L104 C213 C193 L133 L113 L123 L111 C223 L132 L103 C366 C212 C192 L122 L112 L131 C222 L102 C337 C336 C334 C333 EP103 C335 L121 C331 C329 C332 C330 C380 EP100 EP101 CN306 CN307 C231 C242 C233 C241 C232 C246 C245 C236 C244 C235 C243 C234 C266 R305 C403 Q105 Q101 C282 D101 C283 R496 C156 C367 C292 C106 C155 R410 Q111 R226 R216 C116 C256 C290 C111 R351 R211 D206 R361 R221 D106 D205 C265 C105 D201 C186 C185 C184 C154 R225 R215 C115 C291 C255 C288 C264 C104 C183 C153 R224 C350 R214 R402 C114 C289 C254 C286 R365 C281 C263 C103 R409 C182 C152 R412 R223 R405 R364 R213 C113 R407 C287 R411 C253 C368 Q109 Q107 C284 R408 R366 R403 R406 R404 R362 C261 R363 C262 C102 C181 C151 Q103 R222 C101 R212 C112 C285 C252 C251 R483 R452 R484 R453 C406 C374 C370 R401 C323 C322 C321 C320 C325 C326 R139 C324 C314 C313 C312 C311 C316 C317 C315 C135 R499 C136 R487 R456 C134 R464 R463 C132 R460 R491 C133 R492 R461 R300 C304 C303 C302 C301 R393 C381 R302 L301 R306 C306 C308 R313 C131 L100 C383 C404 L302 C384 R493 R308 R315 R396 R304 R309 R303 R462 C382 R394 C305 R498 C405 C402 FB301 R497 R450 R229 R482 D102 D202 D103 D203 D104 D204 D105 R481 R129 R231 R233 R235 R237 R451 R490 R459 R458 R489 R457 R488 R495 R494 L304 L305 L306 L307 L308 L309 L310 L311 L303 D208 1-864-846- 11 (11) D-AMP BOARD (CONDUCTOR SIDE) (CHASSIS) (CHASSIS) (CHASSIS) (CHASSIS) 1 25 2 24 DIGITAL BOARD CNS1101 A SMPS BOARD CNP811 D SMPS BOARD CNP900 E 1 4 3 1 SPK BOARD CNP500 G SPK BOARD CNP510 F 1 8 1 4 A B C D E F 1 2 3 4 5 6 7 D101 D-3 D102 D-3 D103 D-4 D104 D-5 D105 D-5 D106 D-6 D201 D-3 D202 D-4 D203 D-4 D204 D-5 D205 D-6 D206 D-7 D208 D-3 Q101 A-3 Q103 A-3 Q105 A-5 Q107 A-5 Q109 A-6 Q111 A-5 • Semiconductor Location Ref. No. Location (Page 15) (Page 27) (Page 27) (Page 27) (Page 27) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 22 22 STR-KS600PM/KS600PW STR-KS600PM/KS600PW C335 L115 L114 L113 L105 L104 L103 TP123 R384 R383 R347 R345 R327 R326 R317 R124 R119 C319 C328 C190 C325 C326 R316 R123 C324 R382 C323 R381 C337 C336 C320 C321 C322 R329 C200 C136 C146 C186 C272 C176 R206 C271 C166 R196 C106 R237 IC106 C156 C116 L116 L106 D206 D106 C226 C216 R484 R483 R452 R453 C246 C236 C135 C145 C210 C175 R205 C209 C165 R195 R235 C155 C292 C266 R226 R216 C256 C291 D205 D105 C225 C215 R482 R481 R451 R450 C245 C235 C290 C265 R225 C317 C316 R122 R344 TP122 C333 R375 C314 R376 R377 C315 R378 C334 C313 C312 C311 C144 R114 C159 C185 C115 C105 C114 C104 C184 C154 C208 C174 R204 C207 C164 R194 R233 R215 C255 C289 R318 D104 D204 C224 C214 R493 R492 R462 R461 C244 C234 C150 C113 C183 C153 C103 C205 C163 R193 C206 C173 R203 R231 D203 D103 C223 C213 R464 R460 R491 R463 C243 C233 C288 C264 R224 R214 C254 C287 C286 C263 R223 C143 R113 C168 C199 R213 C253 C285 C193 IC105 IC104 IC103 IC110 IC109 C327 R328 C318 R324 R325 C332 C133 C134 C198 R116 L311 L310 L309 L308 L307 L306 C178 C195 C194 C196 EP103 EP102 EP101 EP100 47 16V 50nH 50nH 50nH 50nH 50nH 50nH 0 560 10k 10k 0 0 470 10k 22k 0.1 0.1 0.1 0.1 0.1 470 10k 0.1 560 0.1 0 47 16V 47 16V 0.1 0.1 0.1 0 0.1 0.01 0.1 0.033 0.22 0.22 3.3 0.22 0.22 3.3 1 1k CXD9775M 0.033 1 50nH 50nH P6SMB39AT3 L136 10µH P6SMB39AT3 L126 10µH 1 1 10k 10k 10k 10k 100p 100p 0.01 0.1 0.22 0.22 3.3 0.22 0.22 3.3 1k 0.033 0.0022 0.0022 2.7 2.7 0.0022 0.0022 P6SMB39AT3 L135 10µH P6SMB39AT3 L125 10µH 1 1 10k 10k 10k 10k 100p 100p 0.0022 0.0022 2.7 0.1 0.1 10k 470 47 16V 0 0.1 560 560 0.1 0 47 16V 0.1 0.1 0.1 0.1 22k 47p 0.033 1 1 1 1 0.033 0.033 0.22 0.22 3.3 0.22 0.22 3.3 1k 2.7 0.0022 0.0022 470 P6SMB39AT3 L124 10µH P6SMB39AT3 L134 10µH 1 1 10k 10k 10k 10k 100p 100p 47p 1 0.033 0.033 1 0.22 0.22 3.3 0.22 0.22 3.3 1k P6SMB39AT3 L133 10µH P6SMB39AT3 L123 10µH 1 1 10k 10k 10k 10k 100p 100p 0.0022 0.0022 2.7 2.7 0.0022 0.0022 0.0022 0.0022 2.7 0.1 22k 47p 0.1 2.7 0.0022 0.0022 2200 35V CXD9775M CXD9775M CXD9775M CXD9788AR CXD9788AR 0.1 0 0.1 0 0 47 16V 0.01 0.01 0.1 22k 0 0 0 0 0 0 47p 2200 35V 2200 35V 2200 35V A1 A2 A3 A4 A5 A6 A7 A8 A9 A10 A11 A12 A13 A14 A15 A16 A17 DATA3 BCK LRCK INIT SCDT PGMUTE SOFT MUTE NSP MUTE SCLATCH3 SCSHIFT OVFW XFSO RESET SD SCK NSP MUTE SOFT MUTE PGMUTE SCDT SCSHIFT SCLATCH2 INIT LRCK BCK DATA2 SCK (1/2) STREAM PROCESSOR STREAM PROCESSOR DIGITAL POWER AMP DIGITAL POWER AMP DIGITAL POWER AMP DIGITAL POWER AMP (CHASSIS) (CHASSIS) (CHASSIS) (CHASSIS) • See page 19 for Waveforms. • See page 29 for IC Block Diagrams. 5-11. SCHEMATIC DIAGRAM – D-AMP Board (1/2) – (Page 23) (Page 23) (Page 23) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 23 23 STR-KS600PM/KS600PW STR-KS600PM/KS600PW C329 C331 R309 Q101 Q103 Q111 Q112 Q109 Q110 C158 Q105 Q107 L112 L111 L102 TP121 R406 R404 R403 R401 R400 R396 R395 R393 R323 R321 R319 R315 R314 R313 R311 R310 R308 R306 R305 R304 R303 C392 C301 C309 C310 C188 R348 R322 R121 R346 C306 C308 R374 C305 R373 R372 C304 R371 C330 C302 C303 C142 C182 R229 C139 C141 C131 R129 D208 R494 R495 R496 R497 R498 R499 C402 C403 C404 C405 R302 R351 R300 C406 CNS301 FB301 C373 0.1 C380 C381 C384 C382 C383 R394 C350 C374 C375 C371 C368 C370 C355 R320 R410 R412 R365 R366 C395 C396 C385 R409 R411 R405 R407 R139 C391 R361 R362 R402 C393 R363 C394 R364 D202 D102 C222 R487 R456 C242 C212 R457 R488 C232 C284 C262 R222 R212 C252 C283 D101 D201 C221 C211 R490 R458 R459 R489 C241 C231 C282 C261 R221 R211 C251 C281 C367 C366 CN303 CN305 CN306 IC108 IC102 IC101 CN307 R109 R110 C140 C151 C101 C132 C189 C112 C204 C172 R202 C203 C162 R192 C152 C102 C111 C181 C202 C171 R201 C201 C161 R191 L101 IC303 L301 IC305 X450 L303 L305 L304 Q301 C192 C191 R408 Q108 Q106 Q102 Q104 47 16V 47 16V 0 2SA1602 2SA1602 2SA1602 2SA1602 2SA1602 2SA1602 47 10V 2SA1602 2SA1602 50nH 50nH 50nH 100k 100k 100k 100k 100k 100 100k 22 0 0 100 33 100 100 100 100 470 470 470 470 470 2.2 0.1 0.1 0.1 0.1 470 10k 10k 470 0.1 0.1 0 0.1 560 560 0.1 0 47 16V 0.1 0.1 0.1 0.033 1k 47p 0.1 0.01 1k MA8027-H-TX 15k 15k 15k 15k 15k 15k 100p 100p 100p 0.001 470 470 470 0.0047 25P 22 25V 0.01 5p 0.001 10p L302 1µH 1M 0.1 0.01 100 10V 0.01 0.01 0.1 100 16V 0 100k 100k 100k 100k 2.2 10 2.2 100k 100k 100k 100k 0 2.2 100k 100k 100k 2.2 100k 2.2 100k P6SMB39AT3 L132 10µH P6SMB39AT3 L122 10µH 1 10k 10k 100p 1 10k 10k 100p 0.0022 0.0022 2.7 2.7 0.0022 0.0022 P6SMB39AT3 L121 10µH P6SMB39AT3 L131 10µH 1 1 10k 10k 10k 10k 100p 100p 0.0022 0.0022 2.7 2.7 0.0022 0.0022 0.1 220 16V 3P 4P 4P CXD9788AR CXD9775M CXD9775M 8P 22k 22k 47p 0.033 1 0.01 0.1 1 0.22 0.22 3.3 0.22 0.22 3.3 0.033 1 1 0.033 0.22 0.22 3.3 0.22 0.22 3.3 50nH TK11118CSCL-G 0 MC74VHC1GU04 49.152MHz 0 L100 10µH 0 0 2SC1623-T1-L5L6 2200 35V 2200 35V 100k 2SA1602 2SA1602 2SA1602 2SA1602 A1 A2 A3 A4 A5 A6 A7 A8 A9 A10 A11 A12 A13 A14 A15 A16 A17 INIT SCDT RESET SD BCK LRCK DATA1 BCK LRCK INIT NSP MUTE SOFT MUTE PGMUTE SCDT SOFT MUTE OVF OVF SCLATCH3 SCLATCH2 SCLATCH1 SCSHIFT SCSHIFT SCLATCH1 SCK SCK FAN-CLK FAN-CTRL FAN ON/OFF DATA2 DATA3 OVFW XFSO SD RESET DATA1 D1 D2 D3 BCKO LRCKO DGND SCDT SHIFT DGND LAT1 LAT2 LAT3 INIT 12V GND REST SD DGND SOFT MUTE OVF GND C+ C- 31V 31V 12V SCK FAN-CLK FAN ON/OFF FAN-CTRL DGND OVFW DGND W- W+ 3.3V (2/2) NP CONT +1.8V REGULATOR NC V G I O G OSC BUFFER STREAM PROCESSOR PROTECT DETECT DIGITAL POWER AMP DIGITAL POWER AMP Q101-112 OVER LOAD DETECT LCH+ LCH- RCH+ RCH- LCH+ LCH- RCH+ RCH- • See page 19 for Waveforms. • See page 29 for IC Block Diagrams. 5-12. SCHEMATIC DIAGRAM – D-AMP Board (2/2) – (Page 28) (Page 28) (Page 17) (Page 22) (Page 22) (Page 28) (Page 28) (Page 22) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 24 24 STR-KS600PM/KS600PW STR-KS600PM/KS600PW 5-13. PRINTED WIRING BOARDS – DISPLAY Section – • See page 13 for Circuit Boards Location. : Uses unleaded solder. C700 JW715 D706 L700 D703 D702 C701 D707 Q700 Q701 R700 JW700 JW701 JW702 JW703 JW704 JW705 JW706 JW707 JW708 JW709 JW710 JW711 JW712 JW714 S706 C762 C707 C705 C706 C764 C763 C709 R702 R750 D705 C703 C704 C702 D700 D701 R703 R701 C708 R705 R706 D704 JW719 JW721 JW722 CNS703 JW716 JW717 JW718 JW720 D708 R751 Q710 D710 R710 JW730 CNP702 IC700 E E E 1 1 4 15 34 49 64 65 68 11 33 23 22 12 34 44 1-865-563- 11 (11) DISPLAY BOARD 1 FL700 FLUORESCENT INDICATOR TUBE VIDEO 1 VIDEO 2 DVD TUNER SA-CD/CD 1 9 T700 DC/DC CONVERTER C DIGITAL BOARD CNS193 S700 – 706 T700 2 3 4 6 5 9 1 7 8 S703 S704 S702 S700 S701 S705 RV700 ROTARY ENCODER IC701 R756 C710 R754 R755 R752 R753 JW731 CN701 1-865-562- 11 (11) VOLUME BOARD + – PRESET TUNING MASTER VOLUME 1 3 INPUT SELECTOR SOUND FIELD MUT ING PL II ; 1 1 8 3 A B C D 1 2 3 4 5 6 7 8 9 10 11 D700 B-4 D701 B-4 D702 B-4 D703 B-4 D704 B-5 D705 B-5 D706 B-4 D707 B-3 D708 B-2 D710 B-2 IC700 B-9 IC701 D-6 Q700 B-3 Q701 B-3 Q710 A-2 • Semiconductor Location Ref. No. Location (Page 15) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 25 25 STR-KS600PM/KS600PW STR-KS600PM/KS600PW C701 R700 C700 R701 C703 C702 C704 D704 D701 D700 D702 D703 R703 R702 R710 D707 D706 D705 D708 R751 R750 C763 C762 C764 C708 C709 R706 C705 C706 S706 CNP702 R754 R755 C710 R752 R756 IC701 CNS703 FL700 R705 C707 IC700 T700 D710 Q710 RV700 S700 S702 S704 S703 S705 S701 CN701 R753 Q700 Q701 0.022 1.8k L700 47µH 10 50V 10k 10 50V 0.01 0.1 HZ6.8BP-TK 1SS133T-72 1SS133T-72 1SS133T-72 1SS133T-72 470 470 220 SELS5B23C SELS523C SELS5B23C SELS5B23C 150 82k 220p 220p 1000p 10 50V 0.1 10 0.1 10 50V 8P 1k 1k 47 16V 100 1k RPM7240-H9 17P 10 0.1 PT6315 SELS5B23C-TP15 DTC124ESA-TP 8P 10 2SD1513TP-LK 2SD1513TP-LK VOL2A VOL2B SIRCS AD(2) AD(1) AD(0) +3.3V AD(0) AD(1) AD(2) VOL2A VOL2B SIRCS +3.3V 49 48 47 46 45 44 43 49 48 47 46 45 44 43 4 5 6 7 8 9 10 11 12 34 35 36 37 38 39 40 41 42 34 35 36 37 38 39 40 41 42 4 5 6 7 8 9 10 11 12 GND GND +5V +3.3V(STBY) POWER SW SIRCS GND GND AD(0) AD(1) AD(2) VOL UP VOL DOWN SIRCS +3.3V(STBY) VCC GND VOUT FRUORESCENT INDICATOR TUBE FRUORESCENT INDICATOR TUBE DRIVER,LED DRIVER SA-CD/CD VIDEO 2 VIDEO 1 DVD DC/DC CONVERTER Q700,701 OSC TUNER LED DRIVE REMOTE CONTROL RECEIVER ROTARY ENCODER MASTER VOLUME PL MUTING PRESET TUNING - SOUND FIELD INPUT SELECTOR PRESET TUNING +6.5V FL_LAT FL_CLK FL_DIN VOL_JOG(2A) VOL_JOG(2B) AD2 AD1 AD0 TUNER_LED + • See page 19 for Waveforms. • See page 29 for IC Block Diagrams. 5-14. SCHEMATIC DIAGRAM – DISPLAY Section – (Page 18) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 26 26 STR-KS600PM/KS600PW STR-KS600PM/KS600PW SMPS BOARD (COMPONENT SIDE) 1-864-847- 12 (12) A B C D E 1 2 3 4 5 6 7 8 5-15. PRINTED WIRING BOARD – SPEAKER OUT, POWER SUPPLY Section (1/2) – • See page 13 for Circuit Boards Location. : Uses unleaded solder. w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 27 27 STR-KS600PM/KS600PW STR-KS600PM/KS600PW CN820 T910 F901 CNP901 LF902 LINE FILTER C801 D901 PC802 C903 C905 TH901 C803 C804 C805 C910 R920 R921 IC910 D921 L820 IC821 IC801 IC820 IC930 Q911 PC803 PC801 L821 EP801 EP901 C828 C904 C902 C930 C806 C912 C916 R911 R912 C933 C937 C931 C830 C811 C829 L801 R501 C834 D801 C832 R933 D830 D822 D821 D902 D903 C932 R931 D831 C827 C823 D823 C913 T920 C920 CNP900 CNP811 R913 Q910 C917 R914 R915 C919 D915 C918 D910 D931 R930 D930 D911 D912 D913 R916 R918 R917 D914 D919 D918 D934 D917 D920 D933 R919 R938 R939 C938 C935 Q802 Q930 R934 C934 C936 R936 R935 D935 R932 D932 R937 R940 R826 R827 R828 IC822 R803 R802 R807 C808 R801 C802 R805 R806 R804 R820 R821 R823 R824 C809 IC802 R811 Q822 R810 R813 R814 Q801 R815 C810 R812 Q803 R829 R830 Q931 D916 R950 D811 R905 R903 R904 L827 L828 L830 L829 L825 R809R808 Q821 D820 Q820 C831 C820 C824 C833 SMPS BOARD (CONDUCTOR SIDE) 1-864-847- 12 (12) (CHASSIS) E E E E E E E E (CHASSIS) B DIGITAL BOARD CNP110 11 1 E D-AMP BOARD CNP305 4 1 MAIN POWER TRANSFORMER SUB POWER TRANSFORMER B 8 5 1 1 4 4 2 3 1 1 3 4 2 3 1 5 1 5 1 5 1 3 C E D D-AMP BOARD CN303 1 2 EP500 CNP500 CNP510 C500 C502 C503 C504 C505 C506 C508 C509 C510 C511 C512 C513 C515 C501 C514 C507 1 4 1 8 SPK BOARD (CONDUCTOR SIDE) 1-864-848- 12 (12) + – – + SURR L FRONT L + – – + SUBWOOFER CENTER SPEAKERS TM500 + – – + SURR R FRONT R (CHASSIS) F D-AMP BOARD CN306 G D-AMP BOARD CN307 SPK BOARD (COMPONENT SIDE) 1-864-848- 12 (12) CNP502 C551 LF501 LINE FILTER CN501 (AC IN) LINE FILTER BOARD 1-866-524- 12 (12) 1 2 1 2 E A B C D E F G 1 2 3 4 5 6 7 8 9 10 11 12 13 1 4 2 3 D933 E-3 D934 F-3 D935 E-4 IC801 B-3 IC802 B-2 IC820 C-2 IC821 C-3 IC822 D-3 IC910 E-5 IC930 E-3 PC801 D-2 PC802 C-6 PC803 D-2 Q801 B-3 Q802 B-3 Q803 C-2 Q820 D-2 Q821 B-3 Q822 B-3 Q910 E-4 Q911 E-3 Q930 F-3 Q931 E-3 Ref. No. Location Ref. No. Location D801 B-4 D811 C-3 D820 C-2 D821 C-2 D822 C-3 D823 C-3 D830 D-3 D831 D-3 D901 D-7 D902 C-7 D903 C-6 D910 E-4 D911 F-5 D912 F-4 D913 F-5 D914 E-4 D915 E-5 D916 E-3 D917 E-3 D918 E-3 D919 E-4 D920 E-4 D921 E-5 D930 E-4 D931 E-4 D932 E-2 • Semiconductor Location (Page 15) (Page 21) (Page 21) (Page 21) (Page 21) 5-16. PRINTED WIRING BOARDS – SPEAKER OUT, POWER SUPPLY Section (2/2) – • See page 13 for Circuit Boards Location. : Uses unleaded solder. w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 28 28 STR-KS600PM/KS600PW STR-KS600PM/KS600PW TP905 L801 10µH CNP900 CNP811 CN820 L829 10µH Q822 C829 Q821 C828 R829 R828 R826 R830 R827 IC822 D831 R824 R823 C827 D823 D822 IC821 IC820 R820 R821 C823 D821 D820 R815 R812 D811 R814 C811 R813 C810 R810 R811 C809 C802 R801 R803 R802 R804 R805 C808 R807 IC801 Q801 R808 R809 C820 C831 C832 C824 C833 C834 Q820 C801 C805 C806 C804 C803 D921 TP904 TP907 TP906 C910 D903 D902 C905 LF902 TP902 C903 TP901 C904 D917 R918 D918 D919 D920 R919 D915 D914 C919 R917 D916 D913 R930 D931 R950 D930 R914 C917 R915 C916 D910 C912 C918 C913 R913 IC910 R904 R903 R905 C932 R933 C933 C934 R934 D933 IC930 R935 C935 R936 R937 C937 R938 D935 C938 R939 C931 D932 R932 R931 D830 C830 R940 PC802 PC803 C930 PC801 TM500 C500 C501 C514 C515 C502 C503 C504 C505 C506 C507 C508 C509 C510 C511 C513 C512 CNP510 CNP500 LF501 C551 CNP502 EP801 Q803 R806 EP500 R912 R911 D911 D912 Q910 Q911 R921 R920 C920 TH901 D901 CNP901 F901 TP903 C902 R501 CN501 T910 T920 D801 R916 Q930 Q931 D934 C936 Q802 IC802 4P 3P 11P 2SC2412K 1 50V 2SC2412K 220 10V 100k 5.6k 470 330k L830 10µH L825 10µH L828 10µH L827 10µH 12k SI-3025KS 11EQS04-TB5 0 0 1000 16V AL01Z 11EQS04-TB5 L821 220µH SI-8120S SI-8033JF 100 100 3300 10V AL01Z EC10QS04 L820 220µH 10k 1k UDZS6.8B 1M 22 50V 4.7k 0.1 2.2k 47k 0.01 0.022 10k 2.7k 2.2k 10k 470 0.0033 220k SE-B2 2SC2412K 2.2k 3.3k 0.1 0.1 10 50V 0.1 0.1 10 50V DTC114EUA 0.047 400V 2200 35V 0.22 2200 35V 2200 35V SARS03 390 450V 10EDB60-TB5 10EDB60-TB5 0.1 250V 0.0022 250V 0.0022 250V EP05FA 10 155355 UDZS20B UDZS20B 33k ISS355 UDZS20B 0.001 10k UDZS15B ISS355 100 ISS355 10k ISS355 1.5k 0.0047 100k 10 50V ISS355 47 35V 220p 470p 2kV 220 STR-F6168 220k 220k 220k 47p 630V 4.7 2.2 50V 680p 1k UDZS5.6B STR-A6159 10k 47p 100k 100k 1 50V 1M UDZS20B 470p 100k 22 50V EP05FA20 10 4.7 11EQS04-TB5 470 25V 1k TLP421 TLP421 0.0022 250V TLP421 0.001 0.001 0.001 0.001 0.001 0.001 0.001 0.001 0.001 0.001 0.001 0.001 0.001 0.001 0.001 0.001 4P 8P 0.33 275V 2P 2SC2412K 6.8k 0.1 5W 0.33 2W ISS355 ISS355 2SB1132 2SD2396H 68k 3W 68k 3W 3300p 630V RBV-606 2P T3.15AL 250V 0.0022 250V 3.3M 1/2W 2P FCH20A15 3.3k 2SC2412K 2SC2412K UDZS5.6B 0.001 2SC2412K BA10358F GND GND 12V 12V P_CONT1 STOP GND GND STBY_4V GND GND GND (CHASSIS) SW+ SW- C+ C- SLCH+ SLCH- SRCH+ SRCH- LCH+ LCH- RCH+ RCH- (CHASSIS) (CHASSIS) (CHASSIS) LIVE NEUTRAL PWM-DA +3.3V +12V Q821,822 AC OFF DETECT 3.3V 31V 31V BUFFER G V +6V REGULATOR Q801,802 BUFFER REF C GND +3.3V REGULATOR +12V REGULATOR +4V REGULATOR POWER ON/OFF CONTROL SPEAKERS ISOLATOR ISOLATOR ISOLATOR Q930,931 OVER CURRENT DETECT SWITCHING REGULATOR SWITCHING REGULATOR B+ SWITCH +20V REGULATOR (AC IN) MAIN POWER TRANSFORMER SUB POWER TRANSFORMER 1 4 3 2 2 3 1 4 2 1 4 3 SWITCHING 5-17. SCHEMATIC DIAGRAM – SPEAKER OUT, POWER SUPPLY Section – • See page 29 for IC Block Diagrams. (Page 23) (Page 23) (Page 18) (Page 23) (Page 23) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 29 STR-KS600PM/KS600PW IC1131 BR24L16F-WE2 • IC Block Diagrams – DIGITAL Board – 1 2 3 4 5 7 8 A0 A1 A2 GND Vcc WP SCL SDA 1kbit EEPROM ARRAY 7bit 8bit ADDRESS DECODER SLAVE/ WORD ADDRESS REGISTER HIGH-VOLTAGE GENERATOR POWER SUPPLY VOLTAGE DETECTOR DATA REGISTER START STOP ACK CONTROL CIRCUIT 6 7bit IC1301 LC89056W-E 38 37 36 23 24 1 2 3 4 5 44 8 9 10 46 17 22 21 20 30 35 25 26 27 28 29 32 33 34 16 45 13 14 15 47 40 41 48 CL 39 XSEL CE DI EMPHA AUDIO DISEL DOUT DINO DINI DIN2 6 DGND 7 DVDD 11 AVDD 12 AGND DOSEL0 R VIN LPF CKSEL0 XSTATE 18 DGND 19 DVDD XIN XOUT XMCK XSEL 31 DGND DO CSFLAG F0 F1 F2 VF ERR9P BPSYNC ERROR DATAO DOSEL1 CKOUT BCK LRCK CKSEL1 MODE0 MODE1 42 DGND 43 DVDD XMODE TIMING MICROCOMPUTER INTERFACE SAMPLING FREQUENCY C BIT DETECT PA/PB DETECT LOCK DETECT INPUT CIRCUIT DATA DEMODULATOR PLL X’ TAL IC1503 TC7WH157FU (TE12R) SELECT 116 ST 117 A 1 2 3 A B Y 5 Y B GND 4 VCC 8 Y EN G Y www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 30 STR-KS600PM/KS600PW IC1710 MC14052 BDR2 IC1602 PCM1800E/2K SINGLE-END DEFERENTIAL CONVERTER REFERENCE SINGLE-END DEFERENTIAL CONVERTER DIGITAL ∑ MODULATOR DIGITAL ∑ MODULATOR 1/64 DECIMATION FILTER & LOW-CUT FILTER CLOCK/ TIMING CONTROL RESET/ POWER CONTROL SERIAL I/O INTERFACE & MODE/FORMAT CONTROL LIN V REF 1 REFCOM V REF 2 RIN RSTB FMT0 BYPASS FMT1 MODE1 MODE0 FSYNC 1 2 3 4 5 6 8 7 9 11 10 12 AGND VCC C PR C NR C PR C NR DGND SYSCLK DOUT BCK LRCK VDD 24 23 22 21 20 19 17 16 15 14 13 18 1 2 3 4 5 6 7 8 16 15 14 13 12 11 10 9 2X0 X2 VDD X1 XCOM X0 X3 A B VSS VEE INH 2X1 2X3 2XCOM 2X2 IC101 – 106 CXD9775M – D-AMP Board – RESET 4 GND 1 GND 3 PWM BP 2 DREG RTN 5 GVDD 6 M3 7 M1 10 M2 11 DVDD 12 DREG 8 DGND 9 DGND 14 GND 16 GND 18 PWM RECEIVER TIMING CONTROL CLOCK (TCB) SD 13 OTW 15 DIGITAL REGULATOR PROTECTION LOGIC OT & UVP DVDD LOGIC SUPPLY LOGIC SUPPLY DGND PWM AP 17 PWM RECEIVER DVDD DGND DREG GVDD DREG GVDD B 35 GVDD B 36 BST B 33 PVDD B 32 PVDD B 31 OUT B 30 OUT B 29 GND 28 GND 34 TIMING CONTROL CLOCK (TCB) GATE DRIVE HS GVDD A 20 GVDD A 19 BST A 22 PVDD A 23 PVDD A 24 OUT A 25 OUT A 26 GND 27 GND 21 GATE DRIVE LS GVDD GVDD GATE DRIVE HS GATE DRIVE LS www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 31 STR-KS600PM/KS600PW IC108 – 110 CXD9788AR 12 11 10 9 8 7 6 5 4 3 VSUBC XVSS OUTR2 VSSR OUTR1 VDDR VSSL VSSR OUTL2 OUTL1 VSSL VDDL 2 1 PWM CLOCK GENERATOR (SECONDARY) CLOCK GENERATOR (PRIMARY) 31 29 25 OVFFLAGL 26 SFLAG 27 INIT 30 S g P GAIN CONTROL INIT/ MUTE SAMPLING RATE CONVERTER FILTER & LOW CUT FILTER LINER INTERPOLATOR ∆ Σ 48 XFSOIN 47 XVDD HPVDDL 46 45 HPOUTL1 HPVSSL 44 43 HPOUTL2 HPVDDR 42 41 HPOUTR1 HPVSSR 40 HPOUTR2 39 37 FSOCKO 38 FSOI 13 XOVSS 14 XFSOOUT 15 XOVDD 16 DVDD 17 DVSS 18 NSPMUTE 19 SOFTMUTE 20 PGMUTE SERIAL CONTROLLER 21 SCDT 22 SCSHIFT 23 SCLATCH 24 OVFFLAGR 28 MCKSEL 32 BFVDD 33 BFVSS 34 TEST 35 DVDD 36 XFSIIN LRCK BCK DATA IC303 TK11118CSCL-G 1 2 3 5 4 VCONT GND NP VIN VOUT CONTROL CIRCUIT OVER HEAT & OVER CURRENT PROTECTION BANDGAP REFERENCE www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 32 STR-KS600PM/KS600PW IC700 µPD16315GB-3BS – DISPLAY Board – 5 OSC OSC DATA SELECTOR 6 DOUT 7 DIN 8 CLK 9 STB 10 KEY1 11 KEY2 SERIAL INTERFACE DISPLAY MEMORY 24 BITS x 12 WORDS 24-BIT OUTPUT LATCH 12-BIT SHIFT REGISTER SEGMENT DRIVER TIMING GENERATOR KEY SCAN COMMAND DECODER DIMMING CIRCUIT KEY DATA MEMORY (2 x 16 BITS) 4-BIT LATCH 1 LED1 2 LED2 3 LED3 4 LED4 24 16 16 12 4 8 8 4 8 27 SEG14/KS14 29 SEG16/KS16 30 VEE 28 SEG15/KS15 8 31 SEG17/GRID12 33 SEG19/GRID10 32 SEG18/GRID11 23 SEG10/KS10 24 SEG11/KS11 25 SEG12/KS12 26 SEG13/KS13 22 SEG9/KS9 21 SEG8/KS8 20 SEG7/KS7 19 SEG6/KS6 18 SEG5/KS5 17 SEG4/KS4 16 SEG3/KS3 15 SEG2/KS2 14 SEG1/KS1 MULTIPLEXED DRIVER 34 SEG20/GRID9 35 SEG21/GRID8 36 SEG22/GRID7 37 SEG23/GRID6 39 GRID4 40 GRID3 41 GRID2 42 GRID1 43 VDD 44 VSS 13 VDD 12 VSS 38 SEG24/GRID5 GRID DRIVER IC820 SI-8033JF – SMPS Board – OVER CURRENT PROTECTOR LATCH & DRIVER OVER HEAT PROTECTOR REGULATOR ON/OFF SOFT START + – + – RESET VREF COMPARATOR ERROR AMP OSC 1 VIN 2 SW OUT 3 GND 4 VOS 5 ON/OFF IC821 SI-8120S OVER CURRENT PROTECTOR LATCH & DRIVER OVER HEAT PROTECTOR REGULATOR + – + – RESET VREF COMPARATOR ERROR AMP OSC 1 VIN 2 SW OUT 3 GND 4 VOS 5 S.S IC822 SI-3025KS-TL VC 1 VIN 2 THERMAL SHUT DOWN REGULATOR BLOCK GND 6 GND 5 GND 8 GND 7 VO 3 SENSE 4www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 33 STR-KS600PM/KS600PW IC910 STR-F6168-LF1352 OVER CURRENT PROTECT 2 LOGIC OSC INTERNAL BIAS DELAY DELAY LATCH CURRENT MIRROR OVER CURRENT PROTECT 2 OVER CURRENT PROTECT 1 FEED BACK INH 2 INH 1 BOTTOM SKIP LOGIC OCP/INH 1 S/GND 2 DRAIN 3 VCC 4 FB/OCP 5 UNDER VOLTAGE LOCK OUT OVER LOAD PROTECT THERMAL SHUT DOWN OVER VOLTAGE PROTECT SWITCHING REGULATOR BLOCK IC930 STR-A6159 BUFFER OVER CURRENT PROTECT THERMAL SHUT DOWN BLANKING OFF TIMER DISCHARGE OVER VOLTAGE PROTECT OVER LOAD PROTECT UNDER VOLTAGE LOCK OUT FEED BACK BURST BIAS INTERNAL BIAS DRAIN 8 DRAIN 7 STARTUP 5 NC 6 DRIVE SOURCE/OCP 1 VCC 2 GND 3 FB/OLP 4 DELAY Q S R LATCH PWM LATCH www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 34 STR-KS600PM/KS600PW DIGITAL BOARD IC1301 LC89056W-E (DIGITAL AUDIO INTERFACE RECEIVER) Pin No. Pin Name I/O Description 1 DISEL I Selection signal input terminal of data input terminal Fixed at "L" in this set 2 DOUT O Digital data output to the external output terminal Not used 3 to 5 DIN0 to DIN2 I Digital audio signal input terminal 6 D. GND - Ground terminal 7 DVDD - Power supply terminal (+3.3V) 8 R I Input terminal for VCO gain control Not used 9 VIN I VCO free-run frequency setting terminal 10 LPF O PLL loop filter setting terminal 11 AVDD - Power supply terminal (+3.3V) 12 AGND - Ground terminal 13 CKOUT O Audio clock signal output to the DSP 14 BCK O Bit clock signal output to the DSP 15 LRCK O L/R sampling clock signal output to the DSP 16 DATAO O Audio serial data output to the DSP and system controller 17 XSTATE O Source clock selection monitor output to the system controller 18 DGND - Ground terminal 19 DVDD - Power supply terminal (+3.3V) 20 XMCK O System clock signal (12.288 MHz) output to the A/D converter 21 XOUT O System clock output terminal (12.288 MHz) 22 XIN I System clock input terminal (12.288 MHz) 23 EMPHA O Channel status emphasis information output terminal Not used 24 AUDIO O Channel status bit 1 output to the DSP 25 CSFLAG O Channel status head 40 bit renewal flag output terminal Not used 26 to 29 F0/P0/C0 to F3/P3/C3 O Output terminal of input frequency calculation result Not used 30 DVDD - Power supply terminal (+3.3V) 31 DGND - Ground terminal 32 AUTO O Not used 33 BPSYNC O Non-PCM burst preamble sync signal output terminal Not used 34 ERROR O PLL lock error signal and data error flag output to the DSP and system controller 35 DO O Read data output to the system controller 36 DI I Write data input from the system controller 37 CE I Chip enable signal input from the system controller 38 CLK I Clock signal input from the system controller 39 XSEL I Selection signal input terminal of crystal oscillator frequency Fixed at "H" in this set 40, 41 MODE0, MODE1 I Mode setting terminal Fixed at "L" in this set 42 DGND - Ground terminal 43 DVDD - Power supply terminal (+3.3V) 44, 45 DOSEL0, DOSEL1 I Output data format selection signal input terminal Fixed at "L" in this set 46 CKSEL0 I Output clock selection signal input terminal Fixed at "L" in this set 47 CKSEL1 I Output clock selection signal input terminal Not used 48 XMODE I System reset signal input from the system controller "L": reset • IC Pin Function Description www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 35 STR-KS600PM/KS600PW DIGITAL BOARD IC1501 CXD9720BQ (DIGITAL AUDIO SIGNAL PROCESSOR) Pin No. Pin Name I/O Description 1 VSS - Ground terminal 2 XRST I System reset signal input from the system controller "L": reset 3 EXTIN I Master clock signal input terminal Not used 4 LRCKI3 I L/R sampling clock signal input terminal Not used 5 VDDI - Power supply terminal (+2.6V) 6 BCKI3 I Bit clock signal input terminal Not used 7 PLOCK O Internal PLL lock signal output terminal Not used 8 VSS - Ground terminal 9 MCLK1 I System clock input terminal (13.9 MHz) 10 VDDI - Power supply terminal (+2.6V) 11 VSS - Ground terminal 12 MCLK2 O System clock output terminal (13.9 MHz) 13 MS I Master/slave setting terminal "L": internal clock, "H": external clock Fixed at "L" in this set 14 SCKOUT O System clock output to the stream processor 15 LRCKI1 I L/R sampling clock signal input from the digital audio interface receiver 16 VDDE - Power supply terminal (+3.3V) 17 BCKI1 I Bit clock signal input from the digital audio interface receiver 18 SDI1 I Audio serial data input from the A/D converter 19 LRCKO O L/R sampling clock signal output to the stream processor 20 BCKO O Bit clock signal output to the stream processor 21 VSS - Ground terminal 22 KFSIO I Audio clock signal input from the digital audio interface receiver 23 to 25 SDO1 to SDO3 O Audio serial data output to the stream processor 26 SDO4 O Audio serial data output terminal Not used 27 SPDIF O SPDIF audio signal output terminal Not used 28 LRCKI2 I L/R sampling clock signal input from the digital audio interface receiver 29 BCKI2 I Bit clock signal input from the digital audio interface receiver 30 SDI2 I Audio serial data input from the digital audio interface receiver 31 VSS - Ground terminal 32 HACN O Acknowledge signal output to the system controller 33 HDIN I Serial data input from the system controller 34 HCLK I Serial data transfer clock signal input from the system controller 35 HDOUT O Serial data output to the system controller 36 HCS I Chip select signal input from the system controller 37 GP12 I Write signal input from the system controller 38 GP13 O SD-RAM chip enable output terminal Not used 39 GP14 O Row address strobe signal output terminal Not used 40 VDDI - Power supply terminal (+2.6V) 41 VSS - Ground terminal 42 GP15 O Column address strobe signal output terminal Not used 43 OE0 O Output terminal of data input/output mask Not used 44 CS0 O Chip select signal output to the S-RAM 45 WE0 O Write enable signal output to the S-RAM 46 VDDE - Power supply terminal (+3.3V) 47 WMD1 I External memory wait mode setting terminal Fixed at "H" in this set www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 36 STR-KS600PM/KS600PW Pin No. Pin Name I/O Description 48 VSS - Ground terminal 49 WMD0 I External memory wait mode setting terminal Fixed at "H" in this set 50 PAGE2 O External memory page selection signal output terminal Not used 51 VSS - Ground terminal 52, 53 PAGE1, PAGE0 O External memory page selection signal output terminal Not used 54 BOOT I Boot mode control signal input terminal Not used 55 TST1 O Not used 56 BST I Boot strap signal input from the system controller 57 MOD1 I Operation mode setting terminal "L": enhanced mode, "H": normal mode Fixed at "H" in this set 58 MOD0 I Operation mode setting terminal "L": single chip mode, "H": can not use Fixed at "L" in this set 59 EXLOCK I PLL lock error signal and data error flag input from the digital audio interface receiver 60 VDDI - Power supply terminal (+2.6V) 61 VSS - Ground terminal 62, 63 A17, A16 O Address signal output terminal Not used 64 to 66 A15 to A13 O Address signal output to the S-RAM 67 GP10 I L/R sampling clock signal input terminal Not used 68 DECODE O Read ready signal output to the system controller 69 AUDIO I Channel status bit 1 input from the digital audio interface receiver 70 VDDI - Power supply terminal (+2.6V) 71 VSS - Ground terminal 72 to 75 D15 to D12 I/O Two-way data bus with the S-RAM 76 VDDE - Power supply terminal (+3.3V) 77 to 80 D11 to D8 I/O Two-way data bus with the S-RAM 81 VSS - Ground terminal 82 to 85 A9, A12 to A10 O Address signal output to the S-RAM 86 TDO O Simplicity emulation data output terminal Not used 87 TMS I Simplicity emulation data input start and end terminal Not used 88 XTRST I Simplicity emulation non-sync break signal input terminal Not used 89 TCK I Simplicity emulation clock signal input terminal Not used 90 TDI I Simplicity emulation data input terminal Not used 91 VSS - Ground terminal 92 to 97 A8 to A3 O Address signal output to the S-RAM 98, 99 D7, D6 I/O Two-way data bus with the S-RAM 100 VDDI - Power supply terminal (+2.6V) 101 VSS - Ground terminal 102 to 105 D5 to D2 I/O Two-way data bus with the S-RAM 106 VDDE - Power supply terminal (+3.3V) 107, 108 D1, D0 I/O Two-way data bus with the S-RAM 109, 110 A2, A1 O Address signal output to the S-RAM 111 VSS - Ground terminal 112 A0 O Address signal output to the S-RAM 113 PM I PLL initialize signal input from the system controller 114, 115 SDI3, SDI4 I Audio serial data input terminal Not used 116 SYNC I Sync/non-sync setting terminal "L": sync, "H": non-sync Fixed at "H" in this set www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 37 STR-KS600PM/KS600PW Pin No. Pin Name I/O Description 117 TST2 I Not used 118 GP11 I Not used 119 TST3 I Not used 120 VDDI - Power supply terminal (+2.6V) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 38 STR-KS600PM/KS600PW DIGITAL BOARD IC1601 MB90488BPF-G-111E1 (SYSTEM CONTROLLER) Pin No. Pin Name I/O Description 1 DATAO I Audio serial data input from the digital audio interface receiver 2 GP9 I Read ready signal input from the DSP 3 BST O Boot strap signal output to the DSP 4 HCS O Chip select signal output to the DSP 5 HACN I Acknowledge signal input from the DSP 6 XRST O System reset signal output to the DSP "L": reset 7 PM O PLL initialize signal output to the DSP 8 PWM-DA O Power control signal output terminal 9 GP12 O Write signal output to the DSP 10 AD_RST O Reset signal output to the A/D converter 11 VSS - Ground terminal 12, 13 VIDEO-SW1, VIDEO-SW2 O Video input selection signal output terminal Not used 14 VIDEO-MUTE O Video muting on/off control signal output terminal Not used 15, 16 157_CTL1, 157_CTL2 - Not used 17 WOOFER RELAY - Not used 18 HDOUT I Serial data input from the DSP 19 HDIN O Serial data output to the DSP 20 HCLK O Serial data transfer clock signal output to the DSP 21, 22 SELECT_B, SELECT_A O Analog audio input signal switching signal output terminal 23 VCC5 - Power supply terminal (+3.3V) 24 ANA/DIG O Analog/digital selection signal output terminal "L": analog, "H": digital 25 14052_CTL1 - Not used 26 POWER_SD I Over load detection signal input terminal 27, 28 FLASH2, FLASH1 O Flash programming signal output terminal Not used 29 NC - Not used 30 XSCEN O Chip enable signal output terminal Not used 31 XRST O System reset signal output terminal Not used 32 POWER_RST O Reset signal output to the digital power amplifiers 33 SCL O Serial data transfer clock signal output to the EEPROM 34 SDA I/O Two-way data bus with the EEPROM 35 AVCC - Power supply terminal (+3.3V) 36 AVRH I Reference voltage (+3.3V) input terminal 37 AVSS - Ground terminal 38 to 40 A/D0 to A/D2 I Front panel key input terminal (A/D input) 41 A/D3 I Key input terminal Not used 42 VSS - Ground terminal 43 RDS SIGNAL I RDS signal input from the tuner unit 44 MODEL I Setting terminal for the model (A/D input) 45 VERSION I Setting terminal for the destination (A/D input) 46 P. CONT1 O Power on/off control signal output terminal 47 SMPS RST - Not used 48 STOP P. STOP I AC off detection signal input terminal "L": AC off 49 to 51 MD0 to MD2 I CPU operation mode setting signal terminal www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 39 STR-KS600PM/KS600PW Pin No. Pin Name I/O Description 52 RDS CLK I RDS interrupt clock signal input from the tuner unit 53 RDS DATA I RDS serial data input from the tuner unit 54 SIRCS I SIRCS signal input terminal 55 FUSE DETECT I Fuse open detection signal input terminal "L": fuse opened 56 POWER KEY I Power key input terminal "L": switch on 57 NO USE - Not used 58 to 60 LAT3 to LAT1 O Latch signal output to the stream processor 61 SHIFT O Serial data latch pulse output to the stream processor 62 SCDT O Serial data output to the stream processor 63 SOFT_MUTE O Muting on/off control signal output terminal 64 INT O Initialize signal output to the stream processor 65 STEREO I FM stereo detection signal input from the FM/AM tuner pack 66 TUNED I Tuned detection signal input from the FM/AM tuner pack 67 TUNER_LED O LED drive signal output terminal 68 OVF I Overflow signal input from the stream processor 69 FAN_CTL O Fan motor on/off control signal output terminal Not used 70, 71 VOLB, VOLA I Jog dial pulse input terminal 72 FL_DATA O Serial data output to the fluorescent display tube driver 73 FL_CLK O Serial data transfer clock signal output to the fluorescent indicator tube driver 74 FL_STB O Strobe signal output to the fluorescent indicator tube driver 75 FAN_CLK I Fan motor feedback clock signal input terminal Not used 76 FAN_ON I Fan motor level detection signal input terminal Not used 77 RSTX I System reset signal input from the reset signal generator "L": reset For several hundreds msec. after the power supply rises, "L" is input, then it changes to "H" 78 OVFW I Overflow signal input for subwoofer from the stream processor 79 X1A O Sub system clock output terminal Not used 80 X0A I Sub system clock input terminal Not used 81 VSS - Ground terminal 82 X0 I Main system clock input terminal (24 MHz) 83 X1 O Main system clock output terminal (24 MHz) 84 VCC3 - Power supply terminal (+3.3V) 85 T. CLK O Serial data transfer clock signal output to the FM/AM tuner pack 86 T. DATA O Serial data output to the FM/AM tuner pack 87 SLATCH O Latch signal output to the FM/AM tuner pack 88 T_DO I Serial data input from the FM/AM tuner pack 89 T_MUTE O Muting on/off control signal output terminal 90, 91 TC74AC_A, TC74AC_B - Not used 92 LRCK_SW O L/R sampling clock signal switching signal output terminal 93 XMODE O System reset signal output to the digital audio interface receiver "L": reset 94 CKSEL1 O Output clock selection signal output terminal Not used 95 CLK O Clock signal output to the digital audio interface receiver 96 CE O Chip enable signal output to the digital audio interface receiver 97 D1 O Write data output to the digital audio interface receiver 98 D0 I Read data input from the digital audio interface receiver 99 ERROR I PLL lock error signal and data error flag input from the digital audio interface receiver 100 XSTATE I Source clock selection monitor input from the digital audio interface receiver www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 40 STR-KS600PM/KS600PW SECTION 6 EXPLODED VIEWS Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 1 4-254-448-01 KNOB (SL500), VOLUME 2 4-977-358-01 CUSHION 3 X-2050-915-2 FRONT PANEL ASSY (KS600PM) 3 X-2055-641-1 FRONT PANEL ASSY (KS600PW) 4 A-1097-936-A DISPLAY BOARD, COMPLETE 5 3-087-053-01 +BVTP2.6 (3CR) * 6 3-703-244-00 BUSHING (2104), CORD 07 1-777-071-83 CORD, POWER 8 3-070-883-41 SCREW, TAPPING 9 2-189-343-21 CASE (99BW) * 11 1-400-052-11 FILTER, CLAMP (FERRITE CORE) RV700 1-418-725-51 ENCODER, ROTARY (12 TYPE) (MASTER VOLUME) TN1 1-693-676-11 TUNER #2 7-685-646-79 SCREW +BVTP 3X8 TYPE2 IT-3 6-1. COVER SECTION • Items marked “*” are not stocked since they are seldom required for routine service. Some delay should be anticipated when ordering these items. • The mechanical parts with no reference number in the exploded views are not supplied. • Accessories are given in the last of the electrical parts list. NOTE: • -XX and -X mean standardized parts, so they may have some difference from the original one. • Color Indication of Appearance Parts Example: KNOB, BALANCE (WHITE) . . . (RED) ↑ ↑ Parts Color Cabinet's Color 8 8 7 6 11 9 2 5 5 4 1 2 2 #2 #2 TN1 chassis block not supplied (VOLUME board) not supplied supplied with RV700 3 RV700 #2 #2 The components identified by mark 0 or dotted line with mark 0 are critical for safety. Replace only with part number specified. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 41 STR-KS600PM/KS600PW 6-2. CHASSIS BLOCK Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 51 A-1097-929-A SMPS BOARD, COMPLETE 52 4-857-425-00 BUSHING, 03P INSULATING 53 A-1097-939-A D-AMP BOARD, COMPLETE 54 1-828-650-11 WIRE (FLAT TYPE) (25 CORE) 55 A-1097-941-A DIGITAL BOARD, COMPLETE 56 3-378-435-01 CUSHION, SARANET 57 1-828-980-11 WIRE (FLAT TYPE) (15 CORE) 58 1-828-995-11 WIRE (FLAT TYPE) (17 CORE) 59 2-598-805-01 RADIATION SHEET #1 7-685-645-79 SCREW +BVTP 3X6 TYPE2 IT-3 #2 7-685-646-79 SCREW +BVTP 3X8 TYPE2 IT-3 #3 7-685-647-79 SCREW +BVTP 3X10 TYPE2 IT-3 0F901 1-532-465-33 FUSE (T3.15A/250V) 51 52 53 58 56 59 57 54 55 not supplied not supplied (LINE FILTER board) not supplied not supplied (SPK board) not supplied F901 #2 #1 #3 #1 #1 #1 #2 Ver. 1.1 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 42 STR-KS600PM/KS600PW SECTION 7 ELECTRICAL PARTS LIST Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark A-1097-939-A D-AMP BOARD, COMPLETE *********************** < CAPACITOR > C101 1-164-346-11 CERAMIC CHIP 1uF 16V C102 1-164-346-11 CERAMIC CHIP 1uF 16V C103 1-164-346-11 CERAMIC CHIP 1uF 16V C104 1-164-346-11 CERAMIC CHIP 1uF 16V C105 1-164-346-11 CERAMIC CHIP 1uF 16V C106 1-164-346-11 CERAMIC CHIP 1uF 16V C111 1-164-346-11 CERAMIC CHIP 1uF 16V C112 1-164-346-11 CERAMIC CHIP 1uF 16V C113 1-164-346-11 CERAMIC CHIP 1uF 16V C114 1-164-346-11 CERAMIC CHIP 1uF 16V C115 1-164-346-11 CERAMIC CHIP 1uF 16V C116 1-164-346-11 CERAMIC CHIP 1uF 16V C131 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C132 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C133 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C134 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C135 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C136 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C139 1-162-923-11 CERAMIC CHIP 47PF 5% 50V C140 1-162-923-11 CERAMIC CHIP 47PF 5% 50V C141 1-164-156-11 CERAMIC CHIP 0.1uF 25V C142 1-164-156-11 CERAMIC CHIP 0.1uF 25V C143 1-164-156-11 CERAMIC CHIP 0.1uF 25V C144 1-164-156-11 CERAMIC CHIP 0.1uF 25V C145 1-164-156-11 CERAMIC CHIP 0.1uF 25V C146 1-164-156-11 CERAMIC CHIP 0.1uF 25V C150 1-162-923-11 CERAMIC CHIP 47PF 5% 50V C151 1-115-185-11 CERAMIC CHIP 0.033uF 10% 50V C152 1-115-185-11 CERAMIC CHIP 0.033uF 10% 50V C153 1-115-185-11 CERAMIC CHIP 0.033uF 10% 50V C154 1-115-185-11 CERAMIC CHIP 0.033uF 10% 50V C155 1-115-185-11 CERAMIC CHIP 0.033uF 10% 50V C156 1-115-185-11 CERAMIC CHIP 0.033uF 10% 50V C158 1-126-947-11 ELECT 47uF 20% 35V C159 1-162-923-11 CERAMIC CHIP 47PF 5% 50V C161 1-125-898-11 CERAMIC CHIP 0.22uF 10% 50V C162 1-125-898-11 CERAMIC CHIP 0.22uF 10% 50V C163 1-125-898-11 CERAMIC CHIP 0.22uF 10% 50V C164 1-125-898-11 CERAMIC CHIP 0.22uF 10% 50V C165 1-125-898-11 CERAMIC CHIP 0.22uF 10% 50V C166 1-125-898-11 CERAMIC CHIP 0.22uF 10% 50V C168 1-162-923-11 CERAMIC CHIP 47PF 5% 50V C171 1-125-898-11 CERAMIC CHIP 0.22uF 10% 50V C172 1-125-898-11 CERAMIC CHIP 0.22uF 10% 50V C173 1-125-898-11 CERAMIC CHIP 0.22uF 10% 50V C174 1-125-898-11 CERAMIC CHIP 0.22uF 10% 50V C175 1-125-898-11 CERAMIC CHIP 0.22uF 10% 50V C176 1-125-898-11 CERAMIC CHIP 0.22uF 10% 50V C178 1-162-923-11 CERAMIC CHIP 47PF 5% 50V C181 1-115-185-11 CERAMIC CHIP 0.033uF 10% 50V C182 1-115-185-11 CERAMIC CHIP 0.033uF 10% 50V C183 1-115-185-11 CERAMIC CHIP 0.033uF 10% 50V C184 1-115-185-11 CERAMIC CHIP 0.033uF 10% 50V C185 1-115-185-11 CERAMIC CHIP 0.033uF 10% 50V C186 1-115-185-11 CERAMIC CHIP 0.033uF 10% 50V C188 1-164-156-11 CERAMIC CHIP 0.1uF 25V C189 1-164-156-11 CERAMIC CHIP 0.1uF 25V C190 1-164-156-11 CERAMIC CHIP 0.1uF 25V C191 1-107-898-11 ELECT 2200uF 20% 35V C192 1-107-898-11 ELECT 2200uF 20% 35V C193 1-107-898-11 ELECT 2200uF 20% 35V C194 1-107-898-11 ELECT 2200uF 20% 35V C195 1-107-898-11 ELECT 2200uF 20% 35V C196 1-107-898-11 ELECT 2200uF 20% 35V C198 1-164-156-11 CERAMIC CHIP 0.1uF 25V C199 1-164-156-11 CERAMIC CHIP 0.1uF 25V C200 1-164-156-11 CERAMIC CHIP 0.1uF 25V C201 1-125-898-11 CERAMIC CHIP 0.22uF 10% 50V C202 1-125-898-11 CERAMIC CHIP 0.22uF 10% 50V C203 1-125-898-11 CERAMIC CHIP 0.22uF 10% 50V C204 1-125-898-11 CERAMIC CHIP 0.22uF 10% 50V C205 1-125-898-11 CERAMIC CHIP 0.22uF 10% 50V C206 1-125-898-11 CERAMIC CHIP 0.22uF 10% 50V C207 1-125-898-11 CERAMIC CHIP 0.22uF 10% 50V C208 1-125-898-11 CERAMIC CHIP 0.22uF 10% 50V C209 1-125-898-11 CERAMIC CHIP 0.22uF 10% 50V C210 1-125-898-11 CERAMIC CHIP 0.22uF 10% 50V C211 1-136-177-00 FILM 1uF 5% 50V C212 1-136-177-00 FILM 1uF 5% 50V C213 1-136-177-00 FILM 1uF 5% 50V C214 1-136-177-00 FILM 1uF 5% 50V C215 1-136-177-00 FILM 1uF 5% 50V C216 1-136-177-00 FILM 1uF 5% 50V NOTE: • Due to standardization, replacements in the parts list may be different from the parts specified in the diagrams or the components used on the set. • -XX and -X mean standardized parts, so they may have some difference from the original one. • RESISTORS All resistors are in ohms. METAL: Metal-film resistor. METAL OXIDE: Metal oxide-film resistor. F: nonflammable • Items marked “*” are not stocked since they are seldom required for routine service. Some delay should be anticipated when ordering these items. • SEMICONDUCTORS In each case, u: µ, for example: uA... : µA... uPA... : µPA... uPB... : µPB... uPC... : µPC... uPD... : µPD... • CAPACITORS uF: µF • COILS uH: µH The components identified by mark 0 or dotted line with mark 0 are critical for safety. Replace only with part number specified. When indicating parts by reference number, please include the board. D-AMP www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 43 STR-KS600PM/KS600PW C221 1-136-177-00 FILM 1uF 5% 50V C222 1-136-177-00 FILM 1uF 5% 50V C223 1-136-177-00 FILM 1uF 5% 50V C224 1-136-177-00 FILM 1uF 5% 50V C225 1-136-177-00 FILM 1uF 5% 50V C226 1-136-177-00 FILM 1uF 5% 50V C231 1-162-927-11 CERAMIC CHIP 100PF 5% 50V C232 1-162-927-11 CERAMIC CHIP 100PF 5% 50V C233 1-162-927-11 CERAMIC CHIP 100PF 5% 50V C234 1-162-927-11 CERAMIC CHIP 100PF 5% 50V C235 1-162-927-11 CERAMIC CHIP 100PF 5% 50V C236 1-162-927-11 CERAMIC CHIP 100PF 5% 50V C241 1-162-927-11 CERAMIC CHIP 100PF 5% 50V C242 1-162-927-11 CERAMIC CHIP 100PF 5% 50V C243 1-162-927-11 CERAMIC CHIP 100PF 5% 50V C244 1-162-927-11 CERAMIC CHIP 100PF 5% 50V C245 1-162-927-11 CERAMIC CHIP 100PF 5% 50V C246 1-162-927-11 CERAMIC CHIP 100PF 5% 50V C251 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V C252 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V C253 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V C254 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V C255 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V C256 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V C261 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V C262 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V C263 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V C264 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V C265 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V C266 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V C271 1-125-898-11 CERAMIC CHIP 0.22uF 10% 50V C272 1-125-898-11 CERAMIC CHIP 0.22uF 10% 50V C281 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V C282 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V C283 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V C284 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V C285 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V C286 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V C287 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V C288 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V C289 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V C290 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V C291 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V C292 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V C301 1-164-156-11 CERAMIC CHIP 0.1uF 25V C302 1-164-156-11 CERAMIC CHIP 0.1uF 25V C303 1-164-156-11 CERAMIC CHIP 0.1uF 25V C304 1-164-156-11 CERAMIC CHIP 0.1uF 25V C305 1-164-156-11 CERAMIC CHIP 0.1uF 25V C306 1-164-156-11 CERAMIC CHIP 0.1uF 25V C308 1-164-156-11 CERAMIC CHIP 0.1uF 25V C309 1-164-156-11 CERAMIC CHIP 0.1uF 25V C310 1-164-156-11 CERAMIC CHIP 0.1uF 25V C311 1-164-156-11 CERAMIC CHIP 0.1uF 25V C312 1-164-156-11 CERAMIC CHIP 0.1uF 25V C313 1-164-156-11 CERAMIC CHIP 0.1uF 25V C314 1-164-156-11 CERAMIC CHIP 0.1uF 25V C315 1-164-156-11 CERAMIC CHIP 0.1uF 25V C316 1-164-156-11 CERAMIC CHIP 0.1uF 25V C317 1-164-156-11 CERAMIC CHIP 0.1uF 25V C318 1-164-156-11 CERAMIC CHIP 0.1uF 25V C319 1-164-156-11 CERAMIC CHIP 0.1uF 25V C320 1-164-156-11 CERAMIC CHIP 0.1uF 25V C321 1-164-156-11 CERAMIC CHIP 0.1uF 25V C322 1-164-156-11 CERAMIC CHIP 0.1uF 25V C323 1-164-156-11 CERAMIC CHIP 0.1uF 25V C324 1-164-156-11 CERAMIC CHIP 0.1uF 25V C325 1-164-156-11 CERAMIC CHIP 0.1uF 25V C326 1-164-156-11 CERAMIC CHIP 0.1uF 25V C327 1-164-156-11 CERAMIC CHIP 0.1uF 25V C328 1-164-156-11 CERAMIC CHIP 0.1uF 25V C329 1-126-947-11 ELECT 47uF 20% 35V C330 1-126-947-11 ELECT 47uF 20% 35V C331 1-126-947-11 ELECT 47uF 20% 35V C332 1-126-947-11 ELECT 47uF 20% 35V C333 1-126-947-11 ELECT 47uF 20% 35V C334 1-126-947-11 ELECT 47uF 20% 35V C335 1-126-947-11 ELECT 47uF 20% 35V C336 1-126-947-11 ELECT 47uF 20% 35V C337 1-126-947-11 ELECT 47uF 20% 35V C350 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V C355 1-126-933-11 ELECT 100uF 20% 16V C366 1-126-934-11 ELECT 220uF 20% 16V C367 1-164-156-11 CERAMIC CHIP 0.1uF 25V C368 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C370 1-164-156-11 CERAMIC CHIP 0.1uF 25V C371 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C373 1-130-495-00 MYLAR 0.1uF 5% 50V C374 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C375 1-165-722-11 ELECT 100uF 20% 10V C380 1-104-662-31 ELECT 22uF 20% 25V C381 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C382 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C383 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V C384 1-162-910-11 CERAMIC CHIP 5PF 0.25PF 50V C385 1-164-505-11 CERAMIC CHIP 2.2uF 16V C391 1-164-505-11 CERAMIC CHIP 2.2uF 16V C392 1-164-505-11 CERAMIC CHIP 2.2uF 16V C393 1-164-505-11 CERAMIC CHIP 2.2uF 16V C394 1-164-505-11 CERAMIC CHIP 2.2uF 16V C395 1-164-505-11 CERAMIC CHIP 2.2uF 16V C396 1-117-370-11 CERAMIC CHIP 10uF 10V C402 1-162-927-11 CERAMIC CHIP 100PF 5% 50V C403 1-162-927-11 CERAMIC CHIP 100PF 5% 50V C404 1-162-927-11 CERAMIC CHIP 100PF 5% 50V C405 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C406 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V < CONNECTOR > CNS301 1-779-293-11 CONNECTOR, FFC (LIF (NON-ZIF)) 25P < DIODE > D101 6-500-260-01 DIODE P6SMB39AT3 D102 6-500-260-01 DIODE P6SMB39AT3 D103 6-500-260-01 DIODE P6SMB39AT3 D-AMP www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 44 STR-KS600PM/KS600PW D104 6-500-260-01 DIODE P6SMB39AT3 D105 6-500-260-01 DIODE P6SMB39AT3 D106 6-500-260-01 DIODE P6SMB39AT3 D201 6-500-260-01 DIODE P6SMB39AT3 D202 6-500-260-01 DIODE P6SMB39AT3 D203 6-500-260-01 DIODE P6SMB39AT3 D204 6-500-260-01 DIODE P6SMB39AT3 D205 6-500-260-01 DIODE P6SMB39AT3 D206 6-500-260-01 DIODE P6SMB39AT3 D208 8-719-421-15 DIODE MA8027-L < EARTH TERMINAL > * EP100 1-537-738-21 TERMINAL, EARTH * EP101 1-537-738-21 TERMINAL, EARTH * EP102 1-537-738-21 TERMINAL, EARTH * EP103 1-537-738-21 TERMINAL, EARTH < FERRITE BEAD > FB301 1-400-862-11 BEAD, FERRITE < IC > IC101 6-705-695-01 IC CXD9775M IC102 6-705-695-01 IC CXD9775M IC103 6-705-695-01 IC CXD9775M IC104 6-705-695-01 IC CXD9775M IC105 6-705-695-01 IC CXD9775M IC106 6-705-695-01 IC CXD9775M IC108 6-705-979-01 IC CXD9788AR IC109 6-705-979-01 IC CXD9788AR IC110 6-705-979-01 IC CXD9788AR IC303 6-702-300-01 IC TK11118CSCL-G IC305 6-701-189-01 IC MC74VHC1GU04DFT1 < COIL/JUMPER RESISTOR > L100 1-469-525-11 INDUCTOR 10uH L101 1-456-813-11 COIL, AIR-CORE L102 1-456-813-11 COIL, AIR-CORE L103 1-456-813-11 COIL, AIR-CORE L104 1-456-813-11 COIL, AIR-CORE L105 1-456-813-11 COIL, AIR-CORE L106 1-456-813-11 COIL, AIR-CORE L111 1-456-813-11 COIL, AIR-CORE L112 1-456-813-11 COIL, AIR-CORE L113 1-456-813-11 COIL, AIR-CORE L114 1-456-813-11 COIL, AIR-CORE L115 1-456-813-11 COIL, AIR-CORE L116 1-456-813-11 COIL, AIR-CORE L121 1-456-680-11 INDUCTOR 10uH L122 1-456-680-11 INDUCTOR 10uH L123 1-456-680-11 INDUCTOR 10uH L124 1-456-680-11 INDUCTOR 10uH L125 1-456-680-11 INDUCTOR 10uH L126 1-456-680-11 INDUCTOR 10uH L131 1-456-680-11 INDUCTOR 10uH L132 1-456-680-11 INDUCTOR 10uH L133 1-456-680-11 INDUCTOR 10uH L134 1-456-680-11 INDUCTOR 10uH L135 1-456-680-11 INDUCTOR 10uH L136 1-456-680-11 INDUCTOR 10uH L301 1-216-295-00 SHORT CHIP 0 L302 1-412-939-11 INDUCTOR 1uH L303 1-216-295-00 SHORT CHIP 0 L304 1-216-295-00 SHORT CHIP 0 L305 1-216-295-00 SHORT CHIP 0 L306 1-216-295-00 SHORT CHIP 0 L307 1-216-295-00 SHORT CHIP 0 L308 1-216-295-00 SHORT CHIP 0 L309 1-216-295-00 SHORT CHIP 0 L310 1-216-295-00 SHORT CHIP 0 L311 1-216-295-00 SHORT CHIP 0 < TRANSISTOR > Q101 8-729-602-36 TRANSISTOR 2SA1602-F Q102 8-729-602-36 TRANSISTOR 2SA1602-F Q103 8-729-602-36 TRANSISTOR 2SA1602-F Q104 8-729-602-36 TRANSISTOR 2SA1602-F Q105 8-729-602-36 TRANSISTOR 2SA1602-F Q106 8-729-602-36 TRANSISTOR 2SA1602-F Q107 8-729-602-36 TRANSISTOR 2SA1602-F Q108 8-729-602-36 TRANSISTOR 2SA1602-F Q109 8-729-602-36 TRANSISTOR 2SA1602-F Q110 8-729-602-36 TRANSISTOR 2SA1602-F Q111 8-729-602-36 TRANSISTOR 2SA1602-F Q112 8-729-602-36 TRANSISTOR 2SA1602-F Q301 8-729-120-28 TRANSISTOR 2SC1623-L5L6 < RESISTOR > R109 1-216-837-11 METAL CHIP 22K 5% 1/10W R110 1-216-837-11 METAL CHIP 22K 5% 1/10W R113 1-216-837-11 METAL CHIP 22K 5% 1/10W R114 1-216-837-11 METAL CHIP 22K 5% 1/10W R116 1-216-837-11 METAL CHIP 22K 5% 1/10W R119 1-216-837-11 METAL CHIP 22K 5% 1/10W R121 1-216-833-11 METAL CHIP 10K 5% 1/10W R122 1-216-833-11 METAL CHIP 10K 5% 1/10W R123 1-216-833-11 METAL CHIP 10K 5% 1/10W R124 1-216-833-11 METAL CHIP 10K 5% 1/10W R129 1-216-821-11 METAL CHIP 1K 5% 1/10W R139 1-216-864-11 SHORT CHIP 0 R191 1-220-942-11 METAL CHIP 3.3 1% 1/4W R192 1-220-942-11 METAL CHIP 3.3 1% 1/4W R193 1-220-942-11 METAL CHIP 3.3 1% 1/4W R194 1-220-942-11 METAL CHIP 3.3 1% 1/4W R195 1-220-942-11 METAL CHIP 3.3 1% 1/4W R196 1-220-942-11 METAL CHIP 3.3 1% 1/4W R201 1-220-942-11 METAL CHIP 3.3 1% 1/4W R202 1-220-942-11 METAL CHIP 3.3 1% 1/4W R203 1-220-942-11 METAL CHIP 3.3 1% 1/4W R204 1-220-942-11 METAL CHIP 3.3 1% 1/4W R205 1-220-942-11 METAL CHIP 3.3 1% 1/4W R206 1-220-942-11 METAL CHIP 3.3 1% 1/4W R211 1-216-136-00 RES-CHIP 2.7 5% 1/8W R212 1-216-136-00 RES-CHIP 2.7 5% 1/8W R213 1-216-136-00 RES-CHIP 2.7 5% 1/8W D-AMP www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 45 STR-KS600PM/KS600PW R214 1-216-136-00 RES-CHIP 2.7 5% 1/8W R215 1-216-136-00 RES-CHIP 2.7 5% 1/8W R216 1-216-136-00 RES-CHIP 2.7 5% 1/8W R221 1-216-136-00 RES-CHIP 2.7 5% 1/8W R222 1-216-136-00 RES-CHIP 2.7 5% 1/8W R223 1-216-136-00 RES-CHIP 2.7 5% 1/8W R224 1-216-136-00 RES-CHIP 2.7 5% 1/8W R225 1-216-136-00 RES-CHIP 2.7 5% 1/8W R226 1-216-136-00 RES-CHIP 2.7 5% 1/8W R229 1-216-821-11 METAL CHIP 1K 5% 1/10W R231 1-216-821-11 METAL CHIP 1K 5% 1/10W R233 1-216-821-11 METAL CHIP 1K 5% 1/10W R235 1-216-821-11 METAL CHIP 1K 5% 1/10W R237 1-216-821-11 METAL CHIP 1K 5% 1/10W R300 1-216-817-11 METAL CHIP 470 5% 1/10W R302 1-216-817-11 METAL CHIP 470 5% 1/10W R303 1-216-817-11 METAL CHIP 470 5% 1/10W R304 1-216-817-11 METAL CHIP 470 5% 1/10W R305 1-216-817-11 METAL CHIP 470 5% 1/10W R306 1-216-817-11 METAL CHIP 470 5% 1/10W R308 1-216-817-11 METAL CHIP 470 5% 1/10W R309 1-216-864-11 SHORT CHIP 0 R310 1-216-809-11 METAL CHIP 100 5% 1/10W R311 1-216-809-11 METAL CHIP 100 5% 1/10W R313 1-216-809-11 METAL CHIP 100 5% 1/10W R314 1-216-809-11 METAL CHIP 100 5% 1/10W R315 1-216-803-11 METAL CHIP 33 5% 1/10W R316 1-216-817-11 METAL CHIP 470 5% 1/10W R317 1-216-817-11 METAL CHIP 470 5% 1/10W R318 1-216-817-11 METAL CHIP 470 5% 1/10W R319 1-216-809-11 METAL CHIP 100 5% 1/10W R320 1-216-864-11 SHORT CHIP 0 R321 1-216-864-11 SHORT CHIP 0 R322 1-216-833-11 METAL CHIP 10K 5% 1/10W R323 1-216-864-11 SHORT CHIP 0 R324 1-216-864-11 SHORT CHIP 0 R325 1-216-864-11 SHORT CHIP 0 R326 1-216-864-11 SHORT CHIP 0 R327 1-216-864-11 SHORT CHIP 0 R328 1-216-864-11 SHORT CHIP 0 R329 1-216-864-11 SHORT CHIP 0 R344 1-216-817-11 METAL CHIP 470 5% 1/10W R345 1-216-833-11 METAL CHIP 10K 5% 1/10W R346 1-216-817-11 METAL CHIP 470 5% 1/10W R347 1-216-833-11 METAL CHIP 10K 5% 1/10W R348 1-216-817-11 METAL CHIP 470 5% 1/10W R351 1-216-817-11 METAL CHIP 470 5% 1/10W R361 1-216-845-11 METAL CHIP 100K 5% 1/10W R362 1-216-845-11 METAL CHIP 100K 5% 1/10W R363 1-216-845-11 METAL CHIP 100K 5% 1/10W R364 1-216-845-11 METAL CHIP 100K 5% 1/10W R365 1-216-845-11 METAL CHIP 100K 5% 1/10W R366 1-216-845-11 METAL CHIP 100K 5% 1/10W R371 1-216-864-11 SHORT CHIP 0 R372 1-216-818-11 METAL CHIP 560 5% 1/10W R373 1-216-818-11 METAL CHIP 560 5% 1/10W R374 1-216-864-11 SHORT CHIP 0 R375 1-216-864-11 SHORT CHIP 0 R376 1-216-818-11 METAL CHIP 560 5% 1/10W R377 1-216-818-11 METAL CHIP 560 5% 1/10W R378 1-216-864-11 SHORT CHIP 0 R381 1-216-864-11 SHORT CHIP 0 R382 1-216-818-11 METAL CHIP 560 5% 1/10W R383 1-216-818-11 METAL CHIP 560 5% 1/10W R384 1-216-864-11 SHORT CHIP 0 R393 1-216-801-11 METAL CHIP 22 5% 1/10W R394 1-216-857-11 METAL CHIP 1M 5% 1/10W R395 1-216-845-11 METAL CHIP 100K 5% 1/10W R396 1-216-809-11 METAL CHIP 100 5% 1/10W R400 1-216-845-11 METAL CHIP 100K 5% 1/10W R401 1-216-845-11 METAL CHIP 100K 5% 1/10W R402 1-216-845-11 METAL CHIP 100K 5% 1/10W R403 1-216-845-11 METAL CHIP 100K 5% 1/10W R404 1-216-845-11 METAL CHIP 100K 5% 1/10W R405 1-216-845-11 METAL CHIP 100K 5% 1/10W R406 1-216-845-11 METAL CHIP 100K 5% 1/10W R407 1-216-845-11 METAL CHIP 100K 5% 1/10W R408 1-216-845-11 METAL CHIP 100K 5% 1/10W R409 1-216-845-11 METAL CHIP 100K 5% 1/10W R410 1-216-845-11 METAL CHIP 100K 5% 1/10W R411 1-216-845-11 METAL CHIP 100K 5% 1/10W R412 1-216-845-11 METAL CHIP 100K 5% 1/10W R450 1-216-833-11 METAL CHIP 10K 5% 1/10W R451 1-216-833-11 METAL CHIP 10K 5% 1/10W R452 1-216-833-11 METAL CHIP 10K 5% 1/10W R453 1-216-833-11 METAL CHIP 10K 5% 1/10W R456 1-216-833-11 METAL CHIP 10K 5% 1/10W R457 1-216-833-11 METAL CHIP 10K 5% 1/10W R458 1-216-833-11 METAL CHIP 10K 5% 1/10W R459 1-216-833-11 METAL CHIP 10K 5% 1/10W R460 1-216-833-11 METAL CHIP 10K 5% 1/10W R461 1-216-833-11 METAL CHIP 10K 5% 1/10W R462 1-216-833-11 METAL CHIP 10K 5% 1/10W R463 1-216-833-11 METAL CHIP 10K 5% 1/10W R464 1-216-833-11 METAL CHIP 10K 5% 1/10W R481 1-216-833-11 METAL CHIP 10K 5% 1/10W R482 1-216-833-11 METAL CHIP 10K 5% 1/10W R483 1-216-833-11 METAL CHIP 10K 5% 1/10W R484 1-216-833-11 METAL CHIP 10K 5% 1/10W R487 1-216-833-11 METAL CHIP 10K 5% 1/10W R488 1-216-833-11 METAL CHIP 10K 5% 1/10W R489 1-216-833-11 METAL CHIP 10K 5% 1/10W R490 1-216-833-11 METAL CHIP 10K 5% 1/10W R491 1-216-833-11 METAL CHIP 10K 5% 1/10W R492 1-216-833-11 METAL CHIP 10K 5% 1/10W R493 1-216-833-11 METAL CHIP 10K 5% 1/10W R494 1-216-835-11 METAL CHIP 15K 5% 1/10W R495 1-216-835-11 METAL CHIP 15K 5% 1/10W R496 1-216-835-11 METAL CHIP 15K 5% 1/10W R497 1-216-835-11 METAL CHIP 15K 5% 1/10W R498 1-216-835-11 METAL CHIP 15K 5% 1/10W R499 1-216-835-11 METAL CHIP 15K 5% 1/10W D-AMP www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 46 STR-KS600PM/KS600PW DIGITAL < VIBRATOR > X450 1-795-286-21 VIBRATOR, CRYSTAL (49.152MHz) ************************************************************ A-1097-941-A DIGITAL BOARD, COMPLETE *********************** < CAPACITOR > C1024 1-126-964-11 ELECT 10uF 20% 50V C1025 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1026 1-126-947-11 ELECT 47uF 20% 35V C1031 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1032 1-126-935-11 ELECT 470uF 20% 16V C1033 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1034 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1035 1-126-935-11 ELECT 470uF 20% 16V C1036 1-126-964-11 ELECT 10uF 20% 50V C1065 1-162-960-11 CERAMIC CHIP 220PF 10% 50V C1066 1-162-960-11 CERAMIC CHIP 220PF 10% 50V C1067 1-162-960-11 CERAMIC CHIP 220PF 10% 50V C1068 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1069 1-126-964-11 ELECT 10uF 20% 50V C1100 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1102 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1104 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1105 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1107 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1108 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1121 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1122 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1123 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1124 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1125 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1129 1-162-974-11 CERAMIC CHIP 0.01uF 50V C1130 1-162-974-11 CERAMIC CHIP 0.01uF 50V C1137 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C1138 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1139 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1142 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1163 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1251 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1252 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1299 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1301 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1302 1-162-974-11 CERAMIC CHIP 0.01uF 50V C1303 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1304 1-162-974-11 CERAMIC CHIP 0.01uF 50V C1305 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1306 1-126-947-11 ELECT 47uF 20% 35V C1308 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1309 1-162-918-11 CERAMIC CHIP 18PF 5% 50V C1310 1-162-918-11 CERAMIC CHIP 18PF 5% 50V C1312 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1313 1-162-927-11 CERAMIC CHIP 100PF 5% 50V C1314 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1315 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1330 1-126-964-11 ELECT 10uF 20% 50V C1331 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1404 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1441 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V C1443 1-162-962-11 CERAMIC CHIP 470PF 10% 50V C1483 1-162-962-11 CERAMIC CHIP 470PF 10% 50V C1501 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1502 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1503 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1504 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1505 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1506 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1507 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1508 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1509 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1510 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1511 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1513 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1514 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1515 1-126-935-11 ELECT 470uF 20% 16V C1516 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1517 1-126-935-11 ELECT 470uF 20% 16V C1518 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1519 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1520 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1521 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V C1522 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V C1525 1-126-933-11 ELECT 100uF 20% 16V C1601 1-162-960-11 CERAMIC CHIP 220PF 10% 50V C1602 1-162-960-11 CERAMIC CHIP 220PF 10% 50V C1603 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1604 1-126-933-11 ELECT 100uF 20% 16V C1605 1-126-964-11 ELECT 10uF 20% 50V C1607 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1609 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1610 1-126-947-11 ELECT 47uF 20% 35V C1620 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1651 1-162-960-11 CERAMIC CHIP 220PF 10% 50V C1652 1-162-960-11 CERAMIC CHIP 220PF 10% 50V C1653 1-126-964-11 ELECT 10uF 20% 50V C1654 1-126-967-11 ELECT 47uF 20% 50V C1655 1-126-964-11 ELECT 10uF 20% 50V C1656 1-126-967-11 ELECT 47uF 20% 50V C1657 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1659 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1700 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1701 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1702 1-126-964-11 ELECT 10uF 20% 50V C1703 1-126-965-11 ELECT 22uF 20% 50V C1704 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1705 1-162-905-11 CERAMIC CHIP 1PF 0.25PF 50V C1706 1-126-916-11 ELECT 1000uF 20% 6.3V C1707 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1708 1-162-923-11 CERAMIC CHIP 47PF 5% 50V C1709 1-162-927-11 CERAMIC CHIP 100PF 5% 50V C1710 1-162-927-11 CERAMIC CHIP 100PF 5% 50V C1711 1-162-927-11 CERAMIC CHIP 100PF 5% 50V C1712 1-162-927-11 CERAMIC CHIP 100PF 5% 50V C1713 1-162-927-11 CERAMIC CHIP 100PF 5% 50V D-AMP www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 47 STR-KS600PM/KS600PW C1714 1-162-927-11 CERAMIC CHIP 100PF 5% 50V C1715 1-126-964-11 ELECT 10uF 20% 50V C1716 1-126-964-11 ELECT 10uF 20% 50V C1717 1-126-964-11 ELECT 10uF 20% 50V C1718 1-126-964-11 ELECT 10uF 20% 50V C1719 1-126-964-11 ELECT 10uF 20% 50V C1720 1-126-964-11 ELECT 10uF 20% 50V C1721 1-126-933-11 ELECT 100uF 20% 16V C1722 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1723 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1724 1-126-933-11 ELECT 100uF 20% 16V C1725 1-126-964-11 ELECT 10uF 20% 50V C1726 1-126-933-11 ELECT 100uF 20% 16V C1727 1-126-964-11 ELECT 10uF 20% 50V C1728 1-126-947-11 ELECT 47uF 20% 35V C1729 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1730 1-126-964-11 ELECT 10uF 20% 50V C1731 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1732 1-126-947-11 ELECT 47uF 20% 35V C1936 1-126-967-11 ELECT 47uF 20% 50V < CONNECTOR > CNP110 1-691-773-11 PLUG (MICRO CONNECTOR) 11P CNS192 1-568-826-11 CONNECTOR, FFC 7P CNS193 1-784-778-11 CONNECTOR, FFC 17P CNS195 1-569-321-11 SOCKET, CONNECTOR 15P CNS1101 1-779-293-11 CONNECTOR, FFC (LIF (NON-ZIF)) 25P < DIODE > D1001 8-719-210-39 DIODE EC10QS-04 D1003 8-719-049-09 DIODE 1SS367-T3SONY D1004 8-719-049-09 DIODE 1SS367-T3SONY D1006 8-719-988-61 DIODE 1SS355TE-17 D1103 8-719-988-61 DIODE 1SS355TE-17 D1301 8-719-988-61 DIODE 1SS355TE-17 D1700 8-719-988-61 DIODE 1SS355TE-17 < FERRITE BEAD > FB1101 1-414-235-22 INDUCTOR, FERRITE BEAD FB1102 1-414-235-22 INDUCTOR, FERRITE BEAD FB1301 1-414-235-22 INDUCTOR, FERRITE BEAD FB1302 1-414-235-22 INDUCTOR, FERRITE BEAD FB1305 1-414-235-22 INDUCTOR, FERRITE BEAD FB1308 1-414-235-22 INDUCTOR, FERRITE BEAD FB1312 1-414-235-22 INDUCTOR, FERRITE BEAD FB1313 1-414-235-22 INDUCTOR, FERRITE BEAD FB1501 1-414-235-22 INDUCTOR, FERRITE BEAD FB1502 1-414-235-22 INDUCTOR, FERRITE BEAD FB1503 1-414-235-22 INDUCTOR, FERRITE BEAD FB1511 1-414-235-22 INDUCTOR, FERRITE BEAD FB1700 1-414-235-22 INDUCTOR, FERRITE BEAD FB1701 1-414-235-22 INDUCTOR, FERRITE BEAD FB1702 1-414-235-22 INDUCTOR, FERRITE BEAD FB1703 1-414-235-22 INDUCTOR, FERRITE BEAD FB1704 1-414-235-22 INDUCTOR, FERRITE BEAD FB1705 1-414-235-22 INDUCTOR, FERRITE BEAD < EARTH TERMINAL > * G1000 1-537-738-21 TERMINAL, EARTH < IC > IC1025 8-759-071-48 IC TA7807S IC1031 6-703-547-01 IC TA7805LS IC1034 8-759-835-63 IC NJM2391DL1-26 (TE1) IC1035 6-703-547-01 IC TA7805LS IC1111 6-702-913-01 IC S-80929CNMC-G8ZT2G IC1131 (Not supplied) IC BR24L16F-WE2 IC1301 8-759-825-15 IC LC89056W-E IC1501 6-705-843-01 IC CXD9720BQ IC1502 6-704-037-01 IC IC61LV6416-15TG IC1503 8-759-546-74 IC TC7WH157FU (TE12R) IC1600 8-759-710-97 IC NJM4565M-D IC1601 6-804-834-01 IC MB90488BPF-G-111E1 IC1602 8-759-560-56 IC PCM1800E/2K IC1651 8-759-491-47 IC TC74VHCT08AFT (EL) IC1700 6-600-466-01 IC TORX147L (OPT IN SA-CD/CD) IC1701 6-600-466-01 IC TORX147L (OPT IN VIDEO 2) IC1702 8-759-242-70 IC TC7WU04F IC1710 8-759-385-76 IC MC14052 BDR2 IC1711 6-702-771-01 IC TA78033LS IC1712 6-703-550-01 IC TA7809LS < JACK > J1700 1-793-446-21 JACK, PIN 1P (COAX IN DVD) J1710 1-784-920-11 JACK, PIN 6P (SA-CD/CD, VIDEO 1, VIDEO 2 AUDIO IN) < JUMPER RESISTOR > JR1010 1-211-950-11 SHORT CHIP 0 JR1011 1-211-950-11 SHORT CHIP 0 JR1101 1-216-864-11 SHORT CHIP 0 JR1102 1-216-864-11 SHORT CHIP 0 JR1104 1-216-864-11 SHORT CHIP 0 JR1106 1-216-864-11 SHORT CHIP 0 < COIL > L1600 1-469-525-11 INDUCTOR 10uH L1603 1-469-525-11 INDUCTOR 10uH L1604 1-469-525-11 INDUCTOR 10uH < TRANSISTOR > Q1710 8-729-901-00 TRANSISTOR DTC124EK Q1711 8-729-901-00 TRANSISTOR DTC124EK < RESISTOR > R1041 1-216-809-11 METAL CHIP 100 5% 1/10W R1043 1-216-833-11 METAL CHIP 10K 5% 1/10W R1044 1-216-809-11 METAL CHIP 100 5% 1/10W R1049 1-216-833-11 METAL CHIP 10K 5% 1/10W R1053 1-216-809-11 METAL CHIP 100 5% 1/10W R1054 1-216-833-11 METAL CHIP 10K 5% 1/10W R1055 1-216-833-11 METAL CHIP 10K 5% 1/10W R1056 1-216-833-11 METAL CHIP 10K 5% 1/10W R1058 1-216-813-11 METAL CHIP 220 5% 1/10W DIGITAL www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 48 STR-KS600PM/KS600PW R1059 1-216-813-11 METAL CHIP 220 5% 1/10W R1070 1-216-833-11 METAL CHIP 10K 5% 1/10W R1071 1-216-833-11 METAL CHIP 10K 5% 1/10W R1072 1-216-833-11 METAL CHIP 10K 5% 1/10W R1073 1-216-833-11 METAL CHIP 10K 5% 1/10W R1074 1-216-833-11 METAL CHIP 10K 5% 1/10W R1076 1-216-809-11 METAL CHIP 100 5% 1/10W R1078 1-216-833-11 METAL CHIP 10K 5% 1/10W R1079 1-216-833-11 METAL CHIP 10K 5% 1/10W R1081 1-216-833-11 METAL CHIP 10K 5% 1/10W R1082 1-216-833-11 METAL CHIP 10K 5% 1/10W R1083 1-216-833-11 METAL CHIP 10K 5% 1/10W R1085 1-216-833-11 METAL CHIP 10K 5% 1/10W R1086 1-216-833-11 METAL CHIP 10K 5% 1/10W R1087 1-216-809-11 METAL CHIP 100 5% 1/10W R1088 1-216-833-11 METAL CHIP 10K 5% 1/10W R1089 1-216-833-11 METAL CHIP 10K 5% 1/10W R1091 1-216-833-11 METAL CHIP 10K 5% 1/10W R1092 1-216-833-11 METAL CHIP 10K 5% 1/10W R1096 1-216-833-11 METAL CHIP 10K 5% 1/10W R1097 1-216-845-11 METAL CHIP 100K 5% 1/10W R1105 1-216-833-11 METAL CHIP 10K 5% 1/10W R1113 1-216-809-11 METAL CHIP 100 5% 1/10W R1115 1-216-809-11 METAL CHIP 100 5% 1/10W R1119 1-216-821-11 METAL CHIP 1K 5% 1/10W R1120 1-216-809-11 METAL CHIP 100 5% 1/10W R1121 1-216-809-11 METAL CHIP 100 5% 1/10W R1122 1-216-809-11 METAL CHIP 100 5% 1/10W R1123 1-216-809-11 METAL CHIP 100 5% 1/10W R1124 1-216-809-11 METAL CHIP 100 5% 1/10W R1125 1-216-821-11 METAL CHIP 1K 5% 1/10W R1126 1-216-821-11 METAL CHIP 1K 5% 1/10W R1127 1-216-809-11 METAL CHIP 100 5% 1/10W R1128 1-216-809-11 METAL CHIP 100 5% 1/10W R1129 1-216-809-11 METAL CHIP 100 5% 1/10W R1134 1-216-809-11 METAL CHIP 100 5% 1/10W R1135 1-216-809-11 METAL CHIP 100 5% 1/10W R1136 1-216-809-11 METAL CHIP 100 5% 1/10W R1137 1-216-809-11 METAL CHIP 100 5% 1/10W R1140 1-216-809-11 METAL CHIP 100 5% 1/10W R1142 1-216-809-11 METAL CHIP 100 5% 1/10W R1143 1-216-809-11 METAL CHIP 100 5% 1/10W R1144 1-216-809-11 METAL CHIP 100 5% 1/10W R1149 1-216-809-11 METAL CHIP 100 5% 1/10W R1150 1-216-809-11 METAL CHIP 100 5% 1/10W R1151 1-216-809-11 METAL CHIP 100 5% 1/10W R1158 1-216-827-11 METAL CHIP 3.3K 5% 1/10W R1159 1-216-827-11 METAL CHIP 3.3K 5% 1/10W R1160 1-216-809-11 METAL CHIP 100 5% 1/10W R1161 1-216-809-11 METAL CHIP 100 5% 1/10W R1162 1-216-809-11 METAL CHIP 100 5% 1/10W R1163 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R1165 1-216-864-11 SHORT CHIP 0 R1166 1-216-809-11 METAL CHIP 100 5% 1/10W R1167 1-216-809-11 METAL CHIP 100 5% 1/10W R1168 1-216-809-11 METAL CHIP 100 5% 1/10W R1169 1-216-809-11 METAL CHIP 100 5% 1/10W R1170 1-216-809-11 METAL CHIP 100 5% 1/10W R1171 1-216-809-11 METAL CHIP 100 5% 1/10W R1172 1-216-809-11 METAL CHIP 100 5% 1/10W R1173 1-216-809-11 METAL CHIP 100 5% 1/10W R1174 1-216-809-11 METAL CHIP 100 5% 1/10W R1175 1-216-809-11 METAL CHIP 100 5% 1/10W R1178 1-216-833-11 METAL CHIP 10K 5% 1/10W R1179 1-216-833-11 METAL CHIP 10K 5% 1/10W R1180 1-216-833-11 METAL CHIP 10K 5% 1/10W R1181 1-216-809-11 METAL CHIP 100 5% 1/10W R1182 1-216-809-11 METAL CHIP 100 5% 1/10W R1183 1-216-809-11 METAL CHIP 100 5% 1/10W R1184 1-216-809-11 METAL CHIP 100 5% 1/10W R1185 1-216-809-11 METAL CHIP 100 5% 1/10W R1186 1-216-833-11 METAL CHIP 10K 5% 1/10W R1187 1-216-809-11 METAL CHIP 100 5% 1/10W R1188 1-216-809-11 METAL CHIP 100 5% 1/10W R1189 1-216-833-11 METAL CHIP 10K 5% 1/10W R1190 1-216-833-11 METAL CHIP 10K 5% 1/10W R1191 1-216-809-11 METAL CHIP 100 5% 1/10W R1192 1-216-809-11 METAL CHIP 100 5% 1/10W R1193 1-216-864-11 SHORT CHIP 0 R1195 1-216-809-11 METAL CHIP 100 5% 1/10W R1201 1-216-837-11 METAL CHIP 22K 5% 1/10W R1251 1-216-840-11 METAL CHIP 39K 5% 1/10W R1252 1-216-840-11 METAL CHIP 39K 5% 1/10W R1260 1-216-864-11 SHORT CHIP 0 R1261 1-216-864-11 SHORT CHIP 0 R1301 1-216-830-11 METAL CHIP 5.6K 5% 1/10W R1302 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R1303 1-216-839-11 METAL CHIP 33K 5% 1/10W R1304 1-216-809-11 METAL CHIP 100 5% 1/10W R1305 1-216-817-11 METAL CHIP 470 5% 1/10W R1306 1-216-801-11 METAL CHIP 22 5% 1/10W R1307 1-216-809-11 METAL CHIP 100 5% 1/10W R1308 1-216-809-11 METAL CHIP 100 5% 1/10W R1309 1-216-809-11 METAL CHIP 100 5% 1/10W R1310 1-216-857-11 METAL CHIP 1M 5% 1/10W R1311 1-216-809-11 METAL CHIP 100 5% 1/10W R1312 1-216-809-11 METAL CHIP 100 5% 1/10W R1313 1-216-809-11 METAL CHIP 100 5% 1/10W R1314 1-216-833-11 METAL CHIP 10K 5% 1/10W R1315 1-216-809-11 METAL CHIP 100 5% 1/10W R1316 1-216-809-11 METAL CHIP 100 5% 1/10W R1317 1-216-833-11 METAL CHIP 10K 5% 1/10W R1318 1-216-833-11 METAL CHIP 10K 5% 1/10W R1360 1-216-809-11 METAL CHIP 100 5% 1/10W R1362 1-216-809-11 METAL CHIP 100 5% 1/10W R1501 1-216-809-11 METAL CHIP 100 5% 1/10W R1502 1-216-809-11 METAL CHIP 100 5% 1/10W R1503 1-216-813-11 METAL CHIP 220 5% 1/10W R1504 1-216-809-11 METAL CHIP 100 5% 1/10W R1505 1-216-809-11 METAL CHIP 100 5% 1/10W R1506 1-216-809-11 METAL CHIP 100 5% 1/10W R1508 1-216-809-11 METAL CHIP 100 5% 1/10W R1509 1-216-809-11 METAL CHIP 100 5% 1/10W R1511 1-216-809-11 METAL CHIP 100 5% 1/10W R1512 1-216-821-11 METAL CHIP 1K 5% 1/10W DIGITAL www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 49 STR-KS600PM/KS600PW R1513 1-216-833-11 METAL CHIP 10K 5% 1/10W R1514 1-216-833-11 METAL CHIP 10K 5% 1/10W R1515 1-216-857-11 METAL CHIP 1M 5% 1/10W R1517 1-216-813-11 METAL CHIP 220 5% 1/10W R1518 1-216-813-11 METAL CHIP 220 5% 1/10W R1519 1-216-813-11 METAL CHIP 220 5% 1/10W R1520 1-216-813-11 METAL CHIP 220 5% 1/10W R1521 1-216-813-11 METAL CHIP 220 5% 1/10W R1522 1-216-813-11 METAL CHIP 220 5% 1/10W R1523 1-216-813-11 METAL CHIP 220 5% 1/10W R1525 1-216-813-11 METAL CHIP 220 5% 1/10W R1526 1-216-813-11 METAL CHIP 220 5% 1/10W R1527 1-216-813-11 METAL CHIP 220 5% 1/10W R1528 1-216-813-11 METAL CHIP 220 5% 1/10W R1529 1-216-813-11 METAL CHIP 220 5% 1/10W R1532 1-216-813-11 METAL CHIP 220 5% 1/10W R1533 1-216-813-11 METAL CHIP 220 5% 1/10W R1534 1-216-813-11 METAL CHIP 220 5% 1/10W R1535 1-216-813-11 METAL CHIP 220 5% 1/10W R1536 1-216-813-11 METAL CHIP 220 5% 1/10W R1537 1-216-813-11 METAL CHIP 220 5% 1/10W R1538 1-216-813-11 METAL CHIP 220 5% 1/10W R1539 1-216-813-11 METAL CHIP 220 5% 1/10W R1540 1-216-813-11 METAL CHIP 220 5% 1/10W R1541 1-216-813-11 METAL CHIP 220 5% 1/10W R1542 1-216-813-11 METAL CHIP 220 5% 1/10W R1543 1-216-813-11 METAL CHIP 220 5% 1/10W R1544 1-216-813-11 METAL CHIP 220 5% 1/10W R1545 1-216-813-11 METAL CHIP 220 5% 1/10W R1546 1-216-813-11 METAL CHIP 220 5% 1/10W R1547 1-216-813-11 METAL CHIP 220 5% 1/10W R1548 1-216-813-11 METAL CHIP 220 5% 1/10W R1549 1-216-813-11 METAL CHIP 220 5% 1/10W R1550 1-216-813-11 METAL CHIP 220 5% 1/10W R1551 1-216-813-11 METAL CHIP 220 5% 1/10W R1552 1-216-813-11 METAL CHIP 220 5% 1/10W R1553 1-216-813-11 METAL CHIP 220 5% 1/10W R1554 1-216-813-11 METAL CHIP 220 5% 1/10W R1555 1-216-813-11 METAL CHIP 220 5% 1/10W R1556 1-216-809-11 METAL CHIP 100 5% 1/10W R1570 1-216-833-11 METAL CHIP 10K 5% 1/10W R1571 1-216-833-11 METAL CHIP 10K 5% 1/10W R1572 1-216-833-11 METAL CHIP 10K 5% 1/10W R1573 1-216-833-11 METAL CHIP 10K 5% 1/10W R1574 1-216-833-11 METAL CHIP 10K 5% 1/10W R1601 1-216-833-11 METAL CHIP 10K 5% 1/10W R1602 1-216-817-11 METAL CHIP 470 5% 1/10W R1603 1-216-827-11 METAL CHIP 3.3K 5% 1/10W R1604 1-216-821-11 METAL CHIP 1K 5% 1/10W R1605 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R1606 1-216-809-11 METAL CHIP 100 5% 1/10W R1607 1-216-821-11 METAL CHIP 1K 5% 1/10W R1608 1-216-825-11 METAL CHIP 2.2K 5% 1/10W R1610 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R1635 1-216-825-11 METAL CHIP 2.2K 5% 1/10W R1636 1-216-825-11 METAL CHIP 2.2K 5% 1/10W R1651 1-216-833-11 METAL CHIP 10K 5% 1/10W R1652 1-216-833-11 METAL CHIP 10K 5% 1/10W R1653 1-216-827-11 METAL CHIP 3.3K 5% 1/10W R1654 1-216-833-11 METAL CHIP 10K 5% 1/10W R1700 1-216-809-11 METAL CHIP 100 5% 1/10W R1701 1-218-285-11 METAL CHIP 75 5% 1/10W R1702 1-216-821-11 METAL CHIP 1K 5% 1/10W R1703 1-216-837-11 METAL CHIP 22K 5% 1/10W R1704 1-216-854-11 METAL CHIP 560K 5% 1/10W R1705 1-216-809-11 METAL CHIP 100 5% 1/10W R1706 1-216-821-11 METAL CHIP 1K 5% 1/10W R1707 1-216-821-11 METAL CHIP 1K 5% 1/10W R1708 1-216-821-11 METAL CHIP 1K 5% 1/10W R1709 1-216-821-11 METAL CHIP 1K 5% 1/10W R1710 1-216-821-11 METAL CHIP 1K 5% 1/10W R1711 1-216-821-11 METAL CHIP 1K 5% 1/10W R1712 1-216-833-11 METAL CHIP 10K 5% 1/10W R1713 1-216-833-11 METAL CHIP 10K 5% 1/10W R1714 1-216-833-11 METAL CHIP 10K 5% 1/10W R1715 1-216-833-11 METAL CHIP 10K 5% 1/10W R1716 1-216-833-11 METAL CHIP 10K 5% 1/10W R1717 1-216-833-11 METAL CHIP 10K 5% 1/10W R1718 1-216-833-11 METAL CHIP 10K 5% 1/10W R1719 1-216-833-11 METAL CHIP 10K 5% 1/10W R1720 1-216-833-11 METAL CHIP 10K 5% 1/10W R1721 1-216-833-11 METAL CHIP 10K 5% 1/10W R1722 1-216-833-11 METAL CHIP 10K 5% 1/10W R1723 1-216-833-11 METAL CHIP 10K 5% 1/10W R1724 1-216-833-11 METAL CHIP 10K 5% 1/10W R1725 1-216-833-11 METAL CHIP 10K 5% 1/10W R1726 1-216-833-11 METAL CHIP 10K 5% 1/10W R1727 1-216-833-11 METAL CHIP 10K 5% 1/10W R1728 1-216-809-11 METAL CHIP 100 5% 1/10W R1729 1-216-809-11 METAL CHIP 100 5% 1/10W R1730 1-216-833-11 METAL CHIP 10K 5% 1/10W R1731 1-216-833-11 METAL CHIP 10K 5% 1/10W R1732 1-216-833-11 METAL CHIP 10K 5% 1/10W R1733 1-216-833-11 METAL CHIP 10K 5% 1/10W < VIBRATOR > X1101 1-813-448-21 PIEZOELECTRIC OSCILLATOR (24MHz) X1301 1-795-126-21 VIBRATOR, CRYSTAL (12.288MHz) X1502 1-813-276-21 QUARTZ CRYSTAL (13.9MHz) ************************************************************ A-1097-936-A DISPLAY BOARD, COMPLETE ************************ 4-246-476-01 HOLDER (FL) * 4-921-941-01 CUSHION (FL) < CAPACITOR > C700 1-126-795-11 ELECT 10uF 20% 50V C701 1-127-880-11 CERAMIC 0.022uF 10% 50V C702 1-127-876-11 CERAMIC 0.01uF 10% 50V C703 1-126-795-11 ELECT 10uF 20% 50V C704 1-127-888-11 CERAMIC 0.1uF 10% 50V C705 1-127-888-11 CERAMIC 0.1uF 10% 50V C706 1-126-795-11 ELECT 10uF 20% 50V C707 1-127-888-11 CERAMIC 0.1uF 10% 50V DIGITAL DISPLAY www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 50 STR-KS600PM/KS600PW C708 1-126-795-11 ELECT 10uF 20% 50V C709 1-127-888-11 CERAMIC 0.1uF 10% 50V C762 1-128-813-11 CERAMIC 220PF 5% 50V C763 1-128-813-11 CERAMIC 220PF 5% 50V C764 1-128-821-11 CERAMIC 1000PF 5% 50V < CONNECTOR > CNP702 1-784-924-11 PIN, CONNECTOR 8P CNS703 1-784-778-11 CONNECTOR, FFC 17P < DIODE > D700 8-719-991-33 DIODE 1SS133T-77 D701 8-719-991-33 DIODE 1SS133T-77 D702 8-719-991-33 DIODE 1SS133T-77 D703 8-719-991-33 DIODE 1SS133T-77 D704 8-719-068-28 DIODE HZ6.8BP-TK D705 8-719-075-59 LED SELS5B23C-TP15 (VIDEO 1) D706 8-719-075-59 LED SELS5B23C-TP15 (VIDEO 2) D707 8-719-075-59 LED SELS5B23C-TP15 (SA-CD/CD) D708 8-719-075-59 LED SELS5B23C-TP15 (DVD) D710 8-719-075-59 LED SELS5B23C-TP15 (TUNER) < FLUORESCENT INDICATOR TUBE > FL700 1-519-778-11 VACUUM FLUORESCENT DISPLAYS < IC > IC700 8-759-643-83 IC uPD16315GB-3BS < COIL > L700 1-410-517-11 INDUCTOR 47uH < TRANSISTOR > Q700 8-729-045-21 TRANSISTOR 2SD1513TP-LK Q701 8-729-045-21 TRANSISTOR 2SD1513TP-LK Q710 8-729-029-86 TRANSISTOR DTC124ESA < RESISTOR > R700 1-249-420-11 CARBON 1.8K 5% 1/4W R701 1-249-429-11 CARBON 10K 5% 1/4W R702 1-249-413-11 CARBON 470 5% 1/4W R703 1-249-413-11 CARBON 470 5% 1/4W R705 1-249-393-11 CARBON 10 5% 1/4W R706 1-249-393-11 CARBON 10 5% 1/4W R710 1-249-409-11 CARBON 220 5% 1/4W R750 1-249-440-11 CARBON 82K 5% 1/4W R751 1-249-407-11 CARBON 150 5% 1/4W < SWITCH > S706 1-771-349-21 SWITCH, KEYBOARD (I/1) < TRANSFORMER > T700 1-443-300-11 TRANSFORMER, DC-DC CONVERTER ************************************************************ LINE FILTER BOARD ***************** < CAPACITOR > 0C551 1-117-923-11 FILM 0.33uF 20% 275V < CONNECTOR > CNP502 1-564-321-00 PIN, CONNECTOR (3.96mm PITCH) 2P < LINE FILTER > 0LF501 1-456-081-21 COIL, LINE FILTER ************************************************************ A-1097-929-A SMPS BOARD, COMPLETE ********************** 1-533-293-11 FUSE HOLDER 7-685-646-79 SCREW +BVTP 3X8 TYPE2 IT-3 7-685-647-79 SCREW +BVTP 3X10 TYPE2 IT-3 < CAPACITOR > C801 1-130-959-00 FILM 0.047uF 5% 400V C802 1-162-995-11 CERAMIC CHIP 0.022uF 50V C803 1-100-924-21 ELECT 2200uF 20% 35V C804 1-100-924-21 ELECT 2200uF 20% 35V C805 1-100-924-21 ELECT 2200uF 20% 35V C806 1-131-696-11 FILM 0.22uF 5% 50V C808 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V C809 1-162-974-11 CERAMIC CHIP 0.01uF 50V C810 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C811 1-126-965-11 ELECT 22uF 20% 50V C820 1-165-319-11 CERAMIC CHIP 0.1uF 50V C823 1-128-947-31 ELECT 3300uF 20% 10V C824 1-165-319-11 CERAMIC CHIP 0.1uF 50V C827 1-128-950-21 ELECT 1000uF 20% 16V C828 1-137-649-31 ELECT 220uF 20% 10V C829 1-126-960-11 ELECT 1uF 20% 50V C830 1-128-953-31 ELECT 470uF 20% 25V C831 1-165-319-11 CERAMIC CHIP 0.1uF 50V C832 1-126-964-11 ELECT 10uF 20% 50V C833 1-165-319-11 CERAMIC CHIP 0.1uF 50V C834 1-126-964-11 ELECT 10uF 20% 50V 0C902 1-113-920-11 CERAMIC 0.0022uF 20% 250V 0C903 1-113-920-11 CERAMIC 0.0022uF 20% 250V 0C904 1-113-920-11 CERAMIC 0.0022uF 20% 250V 0C905 1-104-705-51 FILM (POWER) 0.1uF 20% 25V 0C910 1-165-911-21 ELECT 390uF 20% 450V 0C912 1-126-947-11 ELECT 47uF 20% 35V 0C913 1-104-332-11 CERAMIC 470PF 10% 2KV 0C916 1-126-964-11 ELECT 10uF 20% 50V 0C917 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V 0C918 1-164-230-11 CERAMIC CHIP 220PF 5% 50V 0C919 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V 0C920 1-117-452-11 FILM 3300PF 5% 630V 0C930 1-113-907-51 CERAMIC 0.0022uF 20% 250V 0C931 1-126-965-11 ELECT 22uF 20% 50V 0C932 1-136-270-11 FILM 47PF 5% 630V 0C933 1-126-961-11 ELECT 2.2uF 20% 50V 0C934 1-162-963-11 CERAMIC CHIP 680PF 10% 50V DISPLAY LINE FILTER SMPS www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 51 STR-KS600PM/KS600PW 0C935 1-162-923-11 CERAMIC CHIP 47PF 5% 50V 0C936 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V 0C937 1-126-960-11 ELECT 1uF 20% 50V 0C938 1-164-315-11 CERAMIC CHIP 470PF 5% 50V < CONNECTOR > CNP811 1-564-506-11 PLUG, CONNECTOR 3P CNP900 1-785-102-11 PIN, CONNECTOR (3.96mm PITCH) 4P * CNP901 1-564-321-21 PIN, CONNECTOR (3.96mm PITCH) 2P < DIODE > D801 8-719-076-60 DIODE FCH20A15 D811 8-719-978-33 DIODE DTZ-TT11-6.8B D820 8-719-210-39 DIODE EC10QS-04 D821 8-719-072-11 DIODE AL01Z-WS D822 8-719-085-36 DIODE 11EQS04-TB5 D823 8-719-072-11 DIODE AL01Z-WS D830 8-719-085-36 DIODE 11EQS04-TB5 D831 8-719-085-36 DIODE 11EQS04-TB5 0D901 6-500-392-01 DIODE RBV-606-01 0D902 6-500-593-21 DIODE 10EDB60-TB5 0D903 6-500-593-21 DIODE 10EDB60-TB5 0D910 8-719-988-61 DIODE 1SS355TE-17 0D911 8-719-988-61 DIODE 1SS355TE-17 0D912 8-719-988-61 DIODE 1SS355TE-17 0D913 8-719-988-61 DIODE 1SS355TE-17 0D914 8-719-083-67 DIODE UDZSTE-1720B 0D915 8-719-988-61 DIODE 1SS355TE-17 0D916 8-719-083-83 DIODE UDZS-TE17-15B 0D917 6-500-108-01 DIODE EP05FA20 0D918 8-719-988-61 DIODE 1SS355TE-17 0D919 8-719-083-67 DIODE UDZSTE-1720B 0D920 8-719-083-67 DIODE UDZSTE-1720B 0D921 6-500-241-01 DIODE SARS03 0D930 8-719-988-61 DIODE 1SS355TE-17 0D931 8-719-988-61 DIODE 1SS355TE-17 0D932 6-500-108-01 DIODE EP05FA20 0D933 8-719-069-55 DIODE UDZSTE-175.6B 0D934 8-719-069-55 DIODE UDZSTE-175.6B 0D935 8-719-083-67 DIODE UDZSTE-1720B < EARTH TERMINAL > * EP801 1-537-738-21 TERMINAL, EARTH * EP901 1-537-738-21 TERMINAL, EARTH < IC > IC801 6-700-388-01 IC SE-B2 IC802 8-759-510-71 IC BA10358F-E2 IC820 6-700-813-01 IC SI-8033JF IC821 6-700-944-01 IC SI-8120S IC822 6-705-642-01 IC SI-3025KS-TL 0IC910 6-707-742-11 IC STR-F6168-LF1352 0IC930 6-704-805-01 IC STR-A6159 < COIL > L801 1-424-860-11 INDUCTOR 10uH L820 1-416-040-11 INDUCTOR 220uH L821 1-416-040-11 INDUCTOR 220uH L825 1-414-398-11 INDUCTOR 10uH L827 1-414-398-11 INDUCTOR 10uH L828 1-414-398-11 INDUCTOR 10uH L829 1-414-398-11 INDUCTOR 10uH L830 1-414-398-11 INDUCTOR 10uH < LINE FILTER > 0LF902 1-428-905-11 COIL, LINE FILTER < IC > 0PC801 8-749-019-04 IC TLP421 0PC802 8-749-019-04 IC TLP421 0PC803 8-749-019-04 IC TLP421 < TRANSISTOR > Q801 8-729-901-81 TRANSISTOR 2SC2412K-T-146-R Q802 8-729-901-81 TRANSISTOR 2SC2412K-T-146-R Q803 8-729-901-81 TRANSISTOR 2SC2412K-T-146-R Q820 8-729-027-43 TRANSISTOR DTC114EKA-T146 Q821 8-729-901-81 TRANSISTOR 2SC2412K-T-146-R Q822 8-729-901-81 TRANSISTOR 2SC2412K-T-146-R 0Q910 8-729-903-46 TRANSISTOR 2SB1132-P 0Q911 8-729-032-65 TRANSISTOR 2SD2396H 0Q930 8-729-901-81 TRANSISTOR 2SC2412K-T-146-R 0Q931 8-729-901-81 TRANSISTOR 2SC2412K-T-146-R < RESISTOR > 0R501 1-219-237-11 SOLID 3.3M 20% 1/2W R801 1-216-833-11 METAL CHIP 10K 5% 1/10W R802 1-216-825-11 METAL CHIP 2.2K 5% 1/10W R803 1-216-826-11 METAL CHIP 2.7K 5% 1/10W R804 1-216-833-11 METAL CHIP 10K 5% 1/10W R805 1-216-817-11 METAL CHIP 470 5% 1/10W R806 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W R807 1-216-849-11 METAL CHIP 220K 5% 1/10W R808 1-216-825-11 METAL CHIP 2.2K 5% 1/10W R809 1-216-827-11 METAL CHIP 3.3K 5% 1/10W R810 1-216-825-11 METAL CHIP 2.2K 5% 1/10W R811 1-216-841-11 METAL CHIP 47K 5% 1/10W R812 1-216-821-11 METAL CHIP 1K 5% 1/10W R813 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R814 1-216-857-11 METAL CHIP 1M 5% 1/10W R815 1-216-833-11 METAL CHIP 10K 5% 1/10W R820 1-216-809-11 METAL CHIP 100 5% 1/10W R821 1-216-809-11 METAL CHIP 100 5% 1/10W R823 1-216-864-11 SHORT CHIP 0 R824 1-216-864-11 SHORT CHIP 0 R826 1-216-817-11 METAL CHIP 470 5% 1/10W R827 1-216-834-11 METAL CHIP 12K 5% 1/10W R828 1-216-830-11 METAL CHIP 5.6K 5% 1/10W R829 1-216-845-11 METAL CHIP 100K 5% 1/10W R830 1-216-851-11 METAL CHIP 330K 5% 1/10W 0R903 1-216-849-11 METAL CHIP 220K 5% 1/10W 0R904 1-216-849-11 METAL CHIP 220K 5% 1/10W 0R905 1-216-849-11 METAL CHIP 220K 5% 1/10W 0R911 1-216-363-00 METAL OXIDE 0.33 5% 2W F SMPS www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 52 STR-KS600PM/KS600PW 0R912 1-214-789-00 METAL 0.1 10% 5W F 0R913 1-216-813-11 METAL CHIP 220 5% 1/10W 0R914 1-216-823-11 METAL CHIP 1.5K 5% 1/10W 0R915 1-216-845-11 METAL CHIP 100K 5% 1/10W 0R916 1-216-827-11 METAL CHIP 3.3K 5% 1/10W 0R917 1-216-833-11 METAL CHIP 10K 5% 1/10W 0R918 1-216-797-11 METAL CHIP 10 5% 1/10W 0R919 1-216-839-11 METAL CHIP 33K 5% 1/10W 0R920 1-215-928-11 METAL OXIDE 68K 5% 3W F 0R921 1-215-928-11 METAL OXIDE 68K 5% 3W F 0R930 1-216-809-11 METAL CHIP 100 5% 1/10W 0R931 1-249-389-11 CARBON 4.7 5% 1/4W 0R932 1-216-797-11 METAL CHIP 10 5% 1/10W 0R933 1-249-389-11 CARBON 4.7 5% 1/4W 0R934 1-216-821-11 METAL CHIP 1K 5% 1/10W 0R935 1-216-833-11 METAL CHIP 10K 5% 1/10W 0R936 1-216-845-11 METAL CHIP 100K 5% 1/10W 0R937 1-216-845-11 METAL CHIP 100K 5% 1/10W 0R938 1-216-857-11 METAL CHIP 1M 5% 1/10W 0R939 1-216-845-11 METAL CHIP 100K 5% 1/10W R940 1-216-821-11 METAL CHIP 1K 5% 1/10W 0R950 1-216-833-11 METAL CHIP 10K 5% 1/10W < TRANSFORMER > 0T910 1-443-590-11 TRANSFORMER, DC CONVERTER 0T920 1-443-591-11 TRANSFORMER, DC CONVERTER < THERMISTOR > 0TH901 1-803-916-11 THERMISTOR, NTC ************************************************************ SPK BOARD ********** < CAPACITOR > C500 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C501 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C502 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C503 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C504 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C505 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C506 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C507 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C508 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C509 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C510 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C511 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C512 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C513 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C514 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C515 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V < CONNECTOR > CNP500 1-691-770-11 PLUG (MICRO CONNECTOR) 8P CNP510 1-691-766-11 PLUG (MICRO CONNECTOR) 4P < TERMINAL > TM500 1-780-266-11 TERMINAL BOARD (FRONT/CENTER/SURR/ SUBWOOFER SPEAKERS) ************************************************************ VOLUME BOARD ************** < CAPACITOR > C710 1-124-589-11 ELECT 47uF 20% 16V < IC > IC701 6-600-309-01 IC RPM7240-H9 < RESISTOR > R752 1-247-807-31 CARBON 100 5% 1/4W R753 1-249-393-11 CARBON 10 5% 1/4W R754 1-249-417-11 CARBON 1K 5% 1/4W R755 1-249-417-11 CARBON 1K 5% 1/4W R756 1-249-417-11 CARBON 1K 5% 1/4W < VARIABLE RESISTOR > RV700 1-418-725-51 ENCODER, ROTARY (12 TYPE) (MASTER VOLUME) < SWITCH > S700 1-771-349-21 SWITCH, KEYBOARD (PRESET TUNING –) S701 1-771-349-21 SWITCH, KEYBOARD (PRESET TUNING +) S702 1-771-349-21 SWITCH, KEYBOARD (MUTING) S703 1-771-349-21 SWITCH, KEYBOARD (SOUND FIELD) S704 1-771-349-21 SWITCH, KEYBOARD (; PL II) S705 1-771-349-21 SWITCH, KEYBOARD (INPUT SELECT) ************************************************************ MISCELLANEOUS ************** 07 1-777-071-83 CORD, POWER * 11 1-400-052-11 FILTER, CLAMP (FERRITE CORE) 54 1-828-650-11 WIRE (FLAT TYPE) (25 CORE) 57 1-828-980-11 WIRE (FLAT TYPE) (15 CORE) 58 1-828-995-11 WIRE (FLAT TYPE) (17 CORE) 0F901 1-532-465-33 FUSE (T3.15A/250V) TN1 1-693-676-11 TUNER ************************************************************ ACCESSORIES ************ 0 1-770-019-61 ADAPTOR, CONVERSION PLUG (UK) SMPS SPK VOLUME www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 53 STR-KS600PM/KS600PW MEMO www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 2 STR-KS600PM/KS600PW REVISION HISTORY Clicking the version allows you to jump to the revised page. Also, clicking the version at the upper right on the revised page allows you to jump to the next revised page. Ver. Date Description of Revision 1.0 2005.06 New 1.1 2006.03 Addition of Ref. No. 59 on EXPLODED VIEWS (SPM-06016) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com
