SERVICE MANUAL Sony Corporation Home Audio Division Published by Sony Techno Create Corporation US Model Canadian Model STR-K900 AEP Model UK Model E Model Australian Model STR-K880 MULTI CHANNEL AV RECEIVER 9-887-101-02 2006E16-1 © 2006.05 Ver. 1.1 2006.05 SPECIFICATIONS STR-K880/K900 • STR-K880 is the tuner and the amplifier section in HT-DDW880, STR-K900 is the tuner and the amplifier section in HT-DDW900. Manufactured under license from Dolby Laboratories. “Dolby”, “Pro Logic” and the double-D symbol are trademarks of Dolby Laboratories. “DTS” and “DTS Digital Surround” are registered trademarks of Digital Theater Systems, Inc. — Continued on next page — POWER OUTPUT AND TOTAL HARMONIC DISTORTION: (Models of area code US only) With 6 ohm loads, both channels driven, from 120 – 20,000 Hz; rated 90 watts per channel minimum RMS power, with no more than 0.7% total harmonic distortion from 250 milliwatts to rated output. Amplifier section Power Output1) Models of area code US, CND (6 ohms 1 kHz, THD 0.7%) FRONT2): 90 W/ch CENTER2): 90 W SUR2) : 90 W/ch (6 ohms 1 kHz, THD 10%) FRONT2): 140 W/ch CENTER2): 140 W SUR2): 140 W/ch 1)Measured under the following conditions: 2)Depending on the sound field settings and the source, there may be no sound output. Inputs (Analog) Area code Power requirements US, CND 120 V AC, 60 Hz MULTI CH IN, SA-CD/CD, MD/TAPE, DVD, VIDEO 1, 2, 3 Sensitivity: 800 mV Impedance: 50 kohms Models of area code AEP, UK, SP, SP6, E51 (6 ohms 1 kHz, THD 0.7%) FRONT2) : 90 W/ch CENTER2): 90 W SUR2) 90 W/ch SUR BACK2): 90 W (6 ohms 1 kHz, THD 10%) FRONT2): 135 W/ch CENTER2): 135 W SUR2): : 135 W/ch SUR BACK2): 135 W Models of area code AUS (6 ohms 120 Hz – 20 kHz, THD 0.09%) FRONT2) : 70 W/ch CENTER2): 70 W SUR2) : 70 W/ch SUR BACK2): 70 W (6 ohms 1 kHz, THD 0.7%) FRONT2) : 90 W/ch CENTER2): 90 W SUR2) : 90 W/ch SUR BACK2): 90 W (6 ohms 1 kHz, THD 10%) FRONT2): 135 W/ch CENTER2): 135 W SUR2): 135 W/ch SUR BACK2): 135 W AEP,UK,SP,SP6 230 V AC, 50 Hz E51, AUS 240 V AC, 50 Hz Inputs (Digital) Outputs (Analog) DVD (Coaxial) Sensitivity: – Impedance: 75 ohms VIDEO 1, 2 (Optical) Sensitivity: – Impedance: – MD/TAPE (OUT), VIDEO 1 (AUDIO OUT) Voltage: 800 mV Impedance: 10 kohms SUB WOOFER Voltage: 2 V Impedance: 1 kohm Photo : STR-K880 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 2 STR-K880/K900 Notes on chip component replacement • Never reuse a disconnected chip component. • Notice that the minus side of a tantalum capacitor may be damaged by heat. UNLEADED SOLDER Boards requiring use of unleaded solder are printed with the lead- free mark (LF) indicating the solder contains no lead. (Caution: Some printed circuit boards may not come printed with the lead free mark due to their particular size) : LEAD FREE MARK Unleaded solder has the following characteristics. • Unleaded solder melts at a temperature about 40 °C higher than ordinary solder. Ordinary soldering irons can be used but the iron tip has to be applied to the solder joint for a slightly longer time. Soldering irons using a temperature regulator should be set to about 350 °C. Caution: The printed pattern (copper foil) may peel away if the heated tip is applied for too long, so be careful! • Strong viscosity Unleaded solder is more viscou-s (sticky, less prone to flow) than ordinary solder so use caution not to let solder bridges occur such as on IC pins, etc. • Usable with ordinary solder It is best to use only unleaded solder but unleaded solder may also be added to ordinary solder. MODEL IDENTIFICATION – Rear Panel – Model Part No. US model 2-663-098-0[] Canadian model 2-663-098-1[] AEP, UK models 2-663-098-2[] E51 model 2-663-098-3[] SP, SP6 models 2-663-098-4[] AUS model 2-663-098-5[] Parts No. • Abbreviation AUS : Australian model CND : Canadian model E51 : Chilean and Peruvian models SP : Singapore model SP6 : Singapore and Malaysia models Reproduction frequency range 28 - 20,000 Hz Tone FM tuner section Tuning range 87.5 - 108.0 MHz Antenna FM wire antenna Antenna terminals 75 ohms, unbalanced Intermediate frequency 10.7 MHz AM tuner section Tuning range Models of area code US, CND With 10-kHz tuning scale: 530 – 1,710 kHz3) With 9-kHz tuning scale: 531 – 1,710 kHz3) Antenna Loop antenna Intermediate frequency 450 kHz 3)You can change the AM tuning scale to 9 kHz or 10 kHz. After tuning in any AM station, turn off the receiver. While holding down TUNING MODE, press ?/1. All preset stations will be erased when you change the tuning scale. To reset the scale to 10 kHz (or 9 kHz), repeat the procedure. Video section Inputs/Outputs Video: 1 Vp-p, 75 ohms COMPONENT VIDEO: Y: 1 Vp-p, 75 ohms PB/CB/B-Y: 0.7 Vp-p, 75 ohms PR/CR/R-Y: 0.7 Vp-p, 75 ohms 80 MHz HD Pass Through Gain levels ±6 dB, 1 dB step General Power requirements Power consumption Power consumption (during standby mode) 0.2 W Dimensions (w/h/d) (Approx.) 430 157.5 316 mm (167/8 62 /8 124/8 inches) including projecting parts and controls Mass (Approx.) 8.0 kg (17 lb 11 oz) Area code Power requirements US, CND 120 V AC, 60 Hz Area code Power consumption US 170 W CND 230 VA Models of area code E51 With 10-kHz tuning scale: 530 – 1,610 kHz3) With 9-kHz tuning scale: 531 – 1,602 kHz3) Models of area code AEP, UK, AUS, SP, SP6 With 9-kHz tuning scale: 531 – 1,602 kHz Antenna Loop antenna Intermediate frequency 450 kHz AEP, UK 230 V AC, 50/60 Hz AUS 240 V AC, 50 Hz SP, SP6 230 – 240 V AC, 50/60 Hz E51 120/220/240 V AC, 50/60 Hz AEP, UK, AUS, SP, SP6, E51 200 W × × × × Design and specifications are subject to change without notice. Ver. 1.1 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 3 STR-K880/K900 TABLE OF CONTENTS 1. GENERAL ................................................................... 4 2. TEST MODE ............................................................... 12 3. DIAGRAMS ................................................................. 14 3-1. Block Diagram – MAIN Section – .................................. 16 3-2. Block Diagram – DISPLAY/POWER Section – ............. 17 3-3. Printed Wiring Board – DIGITAL Board (Side A) –....... 18 3-4. Printed Wiring Board – DIGITAL Board (Side B) –....... 19 3-5. Schematic Diagram – DIGITAL Board (1/5) – ............... 20 3-6. Schematic Diagram – DIGITAL Board (2/5) – ............... 21 3-7. Schematic Diagram – DIGITAL Board (3/5) – ............... 22 3-8. Schematic Diagram – DIGITAL Board (4/5) – ............... 23 3-9. Schematic Diagram – DIGITAL Board (5/5) – ............... 24 3-10. Printed Wiring Board – MAIN Board – .......................... 25 3-11. Schematic Diagram – MAIN Board (1/3) – .................... 26 3-12. Schematic Diagram – MAIN Board (2/3) – .................... 27 3-13. Schematic Diagram – MAIN Board (3/3) – .................... 28 3-14. Printed Wiring Boards – DISPLAY Board, POWER Board – ............................. 29 3-15. Schematic Diagrams – DISPLAY Board, POWER Board – ............................. 30 3-16. Printed Wiring Boards – STANDBY Board, AC SELECT Board – .................... 31 3-17. Printed Wiring Board – SPEAKER Board – ................... 32 3-18. Schematic Diagram – SPEAKER Board, STANDBY Board, AC SELECT Board – ....................... 33 3-19. Printed Wiring Board – SPEAKER B Board – ............... 34 3-20. Printed Wiring Boards – ADCC Board, VIDEO 3 Board – ................................. 35 3-21. Schematic Diagrams – SPEAKER B Board, ADCC Board, VIDEO 3 Board – .................................... 36 3-22. Printed Wiring Boards – VIDEO Board, HEADPHONE Board – ....................... 37 3-23. Schematic Diagram – VIDEO Board, HEADPHONE Board – ....................... 38 3-24. Printed Wiring Board – HDMI Board – .......................... 39 3-25. Schematic Diagram – HDMI Board – ............................. 40 4. EXPLODED VIEWS 4-1. Front Panel Section ......................................................... 49 4-2. Chassis Section-1 ............................................................ 50 4-3. Chassis Section-2 ............................................................ 51 5. ELECTRICAL PARTS LIST .................................. 52 SAFETY CHECK-OUT After correcting the original service problem, perform the following safety check before releasing the set to the customer: Check the antenna terminals, metal trim, “metallized” knobs, screws, and all other exposed metal parts for AC leakage. Check leakage as described below. LEAKAGE TEST The AC leakage from any exposed metal part to earth ground and from all exposed metal parts to any exposed metal part having a return to chassis, must not exceed 0.5 mA (500 microamperes.). Leakage current can be measured by any one of three methods. 1. A commercial leakage tester, such as the Simpson 229 or RCA WT-540A. Follow the manufacturers’ instructions to use these instruments. 2. A battery-operated AC milliammeter. The Data Precision 245 digital multimeter is suitable for this job. 3. Measuring the voltage drop across a resistor by means of a VOM or battery-operated AC voltmeter. The “limit” indication is 0.75 V, so analog meters must have an accurate low-voltage scale. The Simpson 250 and Sanwa SH-63Trd are examples of a passive VOM that is suitable. Nearly all battery operated digital multimeters that have a 2 V AC range are suitable. (See Fig. A) Fig. A. Using an AC voltmeter to check AC leakage. 1.5 kΩ 0.15 µF AC voltmeter (0.75 V) To Exposed Metal Parts on Set Earth Ground SAFETY-RELATED COMPONENT WARNING!! COMPONENTS IDENTIFIED BY MARK 0 OR DOTTED LINE WITH MARK 0 ON THE SCHEMATIC DIAGRAMS AND IN THE PARTS LIST ARE CRITICAL TO SAFE OPERATION. REPLACE THESE COMPONENTS WITH SONY PARTS WHOSE PART NUMBERS APPEAR AS SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUBLISHED BY SONY. ATTENTION AU COMPOSANT AYANT RAPPORT À LA SÉCURITÉ! LES COMPOSANTS IDENTIFIÉS PAR UNE MARQUE 0 SUR LES DIAGRAMMES SCHÉMATIQUES ET LA LISTE DES PIÈCES SONT CRITIQUES POUR LA SÉCURITÉ DE FONCTIONNEMENT. NE REMPLACER CES COM- POSANTS QUE PAR DES PIÈCES SONY DONT LES NUMÉROS SONT DONNÉS DANS CE MANUEL OU DANS LES SUPPLÉMENTS PUBLIÉS PAR SONY. About area codes The area code of the receiver you purchased is shown on the lower right portion of the rear panel (see the illustration below). Any differences in operation, according to the area code, are clearly indicated in the text, for example, “Models of area code AA only”. SPEAKERS FRONT B L R L R CENTER SURROUND BACK SURROUND FRONT A R R L L + – + – SPEAKERS + – Area code www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 4 STR-K880/K900 SECTION 1 GENERAL This section is extracted from instruction manual. Front panel To remove the cover Press PUSH. When you remove the cover, keep it out of reach from children. Receiver ?/1 AUTO CAL MIC SPEAKERS (OFF/A/B/A+B) PHONES VIDEO 3 IN/PORTABLE AV IN VIDEO L AUDIO R MEMORY/ ENTER TUNING MODE TUNING 2CH A.F.D. MOVIE MUSIC MULTI CH IN MUTING DISPLAY INPUT MODE INPUT SELECTOR MASTER VOLUME 1 3 2 5 7 6 4 9 8 q; qa qs ql qd qf qg qh qj PUSH qk Name Function A ?/1 Press to turn the receiver on or off. B SPEAKERS (OFF/A/B/A+B) Press to select OFF, A, B, A+B of the front speakers C Display The current status of the selected component or a list of selectable items appears here. D Remote sensor Receives signals from remote commander. Name Function E DISPLAY Press to select information displayed on the display. F INPUT MODE Press to select the input mode when the same components are connected to both digital and analog jacks. G MASTER VOLUME Turn to adjust the volume level of all speakers at the same time. H MUTING Press to mute the sound. I MULTI CH IN Press to select the audio directly from the components connected to the MULTI CH IN jacks. J INPUT SELECTOR Turn to select the input source to playback. K MOVIE, MUSIC Press to select sound fields (MOVIE, MUSIC). L A.F.D. Press to select A.F.D. mode. M 2CH Press to select 2CH STEREO mode. N TUNING +/– Press to scan a station. O TUNING MODE Press to select the tuning mode. P MEMORY/ENTER Press to store a station or enter the selection when selecting the settings. Q VIDEO 3 IN/ PORTABLE AV IN jacks To connect a camcorder or video game. R AUTO CAL MIC jack Connects to the supplied ECM-AC2 optimizer microphone for the Auto Calibration function. S PHONES jack Connects to a headphone. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 5 STR-K880/K900 About STR-K880 model the indicators on the display MEMORY L C R SL S SR SB SW LFE SP A SP B RDS STEREO MONO D.RANGE NEO:6 SLEEP OPT COAX HDMI 96/24 DIGITAL EX ; DTS-ES ;PRO LOGIC IIx qa q; qg qh qd qf qs 2 1 4 3 5 6 7 8 9 Name Function A SW Lights up when the audio signal is output from the SUB WOOFER jack. B LFE Lights up when the disc being played back contains an LFE (Low Frequency Effect) channel and the LFE channel signal is actually being reproduced. C SP A/SP B Lights up according to the speaker system used. However, these indicators do not light up if the speaker output is turned off or if a headphone is connected. D ;DIGITAL (EX) Lights up when Dolby Digital signals are input. “; DIGITAL EX” lights up when Dolby Digital Surround EX signals are decoded. Note When playing a Dolby Digital format disc, be sure that you have made digital connections and that INPUT MODE is not set to “ANALOG”. Name Function E ;PRO LOGIC (II)/ (IIx) Lights up when the receiver applies Pro Logic processing to 2 channel signals in order to output the center and surround channel signals. “; PRO LOGIC II” lights up when the Pro Logic II Movie/Music/ Game decoder is activated. “; PRO LOGIC IIx” lights up when the Pro Logic IIx Movie/ Music/Game decoder is activated. Note Dolby Pro Logic IIx decoding does not function for DTS format signals or for signals with a sampling frequency of more than 48 kHz. F DTS (-ES)/ (96/24) Lights up when DTS signals are input. “DTS-ES” lights up when DTS-ES signals are input. “DTS 96/24” lights up when the receiver is decoding DTS 96 kHz/24 bit signals. Note When playing a DTS format disc, be sure that you have made digital connections and that INPUT MODE is not set to “ANALOG”. G NEO:6 Lights up when DTS Neo:6 Cinema/Music decoder is activated. H MEMORY Lights up when a memory function, such as Preset Memory, etc., is activated. Name Function * Except for models of area code E51. I Preset station indicators Lights up when using the receiver to tune in radio stations you have preset. For details on presetting radio stations. J Tuner indicators Lights up when using the receiver to tune in radio stations, etc. Note “RDS” appears for models of area code AEP, UK only. K D.RANGE Lights up when dynamic range compression is activated. L HDMI* Flashes when you select “HDMI A.” in the VIDEO menu. M COAX Lights up when INPUT MODE is set to “AUTO” and the source signal is a digital signal being input through the COAXIAL jack, or when INPUT MODE is set to “COAX IN”. N OPT Lights up when INPUT MODE is set to “AUTO” and the source signal is a digital signal being input through the OPTICAL jack, or when INPUT MODE is set to “OPT IN”. O SLEEP Lights up when the sleep timer is activated. P Playback channel indicators L R C SL SR S SB The letters (L, C, R, etc.) indicate the channels being played back. The boxes around the letters vary to show how the receiver downmixes the source sound. Front Left Front Right Center (monaural) Surround Left Surround Right Surround (monaural or the surround components obtained by Pro Logic processing) Surround back (the surround back components obtained by 6.1 channel decoding) Example: Recording format (Front/ Surround): 3/2.1 Sound Field: A.F.D. AUTO L C R SL SR SW www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 6 STR-K880/K900 About STR-K900 model the indicators on the display MEMORY L C R SL S SR SW LFE SP A SP B STEREO MONO D.RANGE SLEEP OPT COAX DIGITAL ; DTS ;PRO LOGIC II q; 9 qf qg qs qd HDMI qa 2 1 4 3 5 6 7 8 Name Function A SW Lights up when the audio signal is output from the SUB WOOFER jack. B LFE Lights up when the disc being played back contains an LFE (Low Frequency Effect) channel and the LFE channel signal is actually being reproduced. C SP A/SP B Lights up according to the speaker system used. However, these indicators do not light up if the speaker output is turned off or if a headphone is connected. D ;DIGITAL Lights up when Dolby Digital signals are input. Note When playing a Dolby Digital format disc, be sure that you have made digital connections and that INPUT MODE is not set to “ANALOG”. E ;PRO LOGIC (II) Lights up when the receiver applies Pro Logic processing to 2 channel signals in order to output the center and surround channel signals. “; PRO LOGIC II” lights up when the Pro Logic II Movie/Music/ Game decoder is activated. Note Dolby Pro Logic and Dolby Pro Logic II decoding do not function for DTS format signals. F DTS Lights up when DTS signals are input. Note When playing a DTS format disc, be sure that you have made digital connections and that INPUT MODE is not set to “ANALOG”. G MEMORY Lights up when a memory function, such as Preset Memory., etc., is activated. H Preset station indicators Lights up when using the receiver to tune in radio stations you have preset. For details on presetting radio stations. I Tuner indicators Lights up when using the receiver to tune in radio stations, etc. J D.RANGE Lights up when dynamic range compression is activated. K HDMI Flashes when you select “HDMI A.” in the VIDEO menu. L COAX Lights up when INPUT MODE is set to “AUTO” and the source signal is a digital signal being input through the COAXIAL jack, or when INPUT MODE is set to “COAX IN”. M OPT Lights up when INPUT MODE is set to “AUTO” and the source signal is a digital signal being input through the OPTICAL jack, or when INPUT MODE is set to “OPT IN”. Name Function N SLEEP Lights up when the sleep timer is activated. O Playback channel indicators L R C SL SR S The letters (L, C, R, etc.) indicate the channels being played back. The boxes around the letters vary to show how the receiver downmixes the source sound. Front Left Front Right Center (monaural) Surround Left Surround Right Surround (monaural or the surround components obtained by Pro Logic processing) Example: Recording format (Front/ Surround): 3/2.1 Sound Field: A.F.D. AUTO Name Function L C R SL SR SW www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 7 STR-K880/K900 Rear STR-K880 model STR-K900 model panel 1 2 3 4 DIGITAL OPTICAL VIDEO 1 IN VIDEO 2 IN DVD IN COAXIAL AM ANTENNA 5 6 VIDEO 1 MULTI CH IN FRONT CENTER SUB WOOFER SURROUND VIDEO IN AUDIO IN AUDIO OUT VIDEO IN VIDEO OUT VIDEO 2 AUDIO IN MD/TAPE SA-CD/CD L R L R L R SUB WOOFER L L R R OUT IN IN VIDEO IN DVD AUDIO IN AUDIO OUT VIDEO OUT DVD IN VIDEO 2 IN MONITOR OUT COMPONENT VIDEO Y ASSIGNABLE PB/CB /B–Y PR/CR /R–Y MONITOR SPEAKERS FRONT B L R L R CENTER SURROUND BACK SURROUND FRONT A R R L L + – + – SPEAKERS + – HDMI DVD IN ASSIGNABLE VIDEO 2 IN MONITOR OUT A DIGITAL INPUT section OPTICAL IN jack Connects to a DVD player, etc. The COAXIAL jack provides a better quality of loud sound. COAXIAL IN jack HDMI IN/ MONITOR OUT jacka)b) Connects to a DVD player, or a satellite tuner. The image and the sound are output to a TV or a projector. B VIDEO/AUDIO INPUT/OUTPUT section AUDIO IN/ OUT jack Connects the video and audio jacks of a VCR or a DVD player. VIDEO IN/ OUT jackb) White (L) Red (R) Yellow 1 6 5 3 4 2 DIGITAL VIDEO 1 IN VIDEO 2 IN DVD IN COAXIAL OPTICAL ANTENNA AM SA-CD/CD MD/TAPE OUT L R R IN IN L L R AUDIO IN VIDEO IN DVD AUDIO IN VIDEO IN VIDEO 2 AUDIO IN VIDEO OUT VIDEO 1 AUDIO OUT VIDEO IN L R VIDEO OUT MONITOR HDMI DVD IN ASSIGNABLE VIDEO 2 IN MONITOR OUT L R SUB WOOFER AUDIO OUT SURROUND SUB WOOFER CENTER MULTI CH IN FRONT DVD IN VIDEO 2 IN MONITOR OUT COMPONENT VIDEO Y ASSIGNABLE PB/CB /B–Y PR/CR /R–Y CENTER + – SPEAKERS SURROUND FRONT A R R L L + – + – SPEAKERS SPEAKERS FRONT B L R L R www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 8 STR-K880/K900 a)Except for models of area code E51. b)You can watch the selected input image when you connect the MONITOR OUT jack to a TV monitor. You can use the supplied remote RM-AAP013 to operate the receiver and to control the Sony audio/video components that the remote is assigned to operate. You can also program the remote to control non-Sony audio/video components. For details, see “Programming the remote”. E AUDIO INPUT/OUTPUT section AUDIO IN/ OUT jack Connects to an MD deck or CD player, etc. MULTI CHANNEL INPUT jack Connects to a Super Audio CD player or DVD player which has an analog audio jack for 5.1 channel sound. F ANTENNA section FM ANTENNA Connects to the FM wire antenna supplied with this receiver. AM ANTENNA Connects to the AM loop antenna supplied with this receiver. White (L) Red (R) White (L) Red (R) Black Remote commander Name Function A AV ?/1 Press to turn on or off the audio/video components that the remote is programmed to operate. If you press ?/1 (B) at the same time, it will turn off the receiver and other components (SYSTEM STANDBY). Note The function of the AV ?/1 switch changes automatically each time you press the input buttons (wj). H X m M . > - VIDEO1 VIDEO2 RM SET UP SYSTEM STANDBY SLEEP TV ?/1 AV ?/1 VIDEO3 DVD MD/TAPE SA-CD/CD TUNER AUX MULTI CH TOP MENU/ GUIDE AV MENU MUTING MASTER VOL DISPLAY TV VOL TV CH WIDE AUTO CAL TV/ VIDEO AMP MENU RETURN/EXIT D.TUNING DISC ALT ANT CLEAR SEARCH MODE 2CH A.F.D. 1 2 3 4 5 6 7 8 9 0/10 >10/11 12 MOVIE SUBTITLE MEMORY ENTER MUSIC AUDIO ANGLE TUNING JUMP/ TIME PRESET/ CH/D.SKIP FM MODE DUAL MONO x ?/1 P O f F G g TV ?/1 (on/standby) switch 8 wl ql wa wd ws w; wg wh wj wk 6 qa 5 7 q; qs qf 9 3 4 AV ?/1 (on/standby) switch ?/1 (on/standby) switch 1 2 qh wf qk qj qd qg C COMPONENT VIDEO INPUT/ OUTPUT section COMPONENT VIDEO INPUT/ OUTPUT jackb) Connects to a DVD player, TV, or a satellite tuner. You can enjoy high quality image. D SPEAKER section Connects to speakers. Connects to sub woofer. Green Blue Red www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 9 STR-K880/K900 Name Function B ?/1 Press to turn the receiver on or off. To turn off all components, press ?/1 and AV ?/1 (A) at the same time (SYSTEM STANDBY). SLEEP Press ALT (G) and then press SLEEP to activate the Sleep Timer function and the duration which the receiver turns off automatically. C MULTI CH Press to select the audio directly from the components connected to the MULTI CH IN jacks. D MUSIC Press to select sound fields (MUSIC). E FM MODE Press to select FM monaural or stereo reception. F PRESET/ CH/D.SKIP +/– Press to – select preset stations. – select preset channels of the TV, VCR, satellite tuner, Blu- ray disc recorder, or hard disc recorder. – skip disc of the CD player, VCD player, DVD player, MD deck, or LD player (multi-disc changer only). G ALT Press to light up the button. It changes the remote key function to activate the buttons with orange printing. H -/-- Press to select the channel entry mode, either one or two digit of the TV, Blu-ray disc recorder, hard disc recorder, PSX, or satellite tuner. DISC Press to select a disc directly of the CD player or VCD player (multi-disc changer only). SEARCH MODE Press to select the searching mode or unit for search (tracks, index, etc.) of the DVD player. I x Press to stop playback of the VCR, CD player, VCD player, LD player, DVD player, MD deck, DAT deck, tape deck, Blu- ray disc recorder, hard disc recorder, or PSX. Name Function J MUTING Press to mute the sound. K MASTER VOL +a)/– Press to adjust the volume level of all speakers at the same time. L AMP MENU Press to display the menu of the receiver. Then, use the control buttons to perform menu operations. M TV/VIDEO Press to select the input signal (TV input or video input). N AUTO CAL Press to activate the Auto Calibration function. O WIDE Press ALT (G) and then press WIDE to select the wide picture mode. P TV CH +a)/– Press to select preset TV channels. Q TV VOL +a)/– Press to adjust the TV volume level. R RETURN/ EXIT O Press to – return to the previous menu. – exit the menu while the menu or on-screen guide of the VCD player, LD player, DVD player, Blu-ray disc recorder, hard disc recorder, PSX, or satellite tuner is displayed on the TV screen. S DISPLAY Press to select information displayed on the TV screen of the TV, VCR, VCD player, LD player, DVD player, CD player, MD deck, Blu-ray disc recorder, hard disc recorder, PSX, or satellite tuner. T Control buttons After pressing AMP MENU (L), TOP MENU/GUIDE (U), or AV MENU (V), press the control button V, v, B or b to select the settings. When you press TOP MENU/GUIDE or AV MENU, press the control button to enter the selection. U TOP MENU/ GUIDE Press to display the – DVD title. – menu or on-screen guide of the satellite tuner, Blu-ray disc recorder, hard disc recorder, or PSX on the TV screen. Then, use the control buttons to perform menu operation. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 10 STR-K880/K900 Name Function V AV MENU Press to display the menus of the VCR, DVD player, satellite tuner, Blu-ray disc recorder, hard disc recorder, or PSX on the TV screen. Then, use the control buttons to perform menu operations. W Ha) Press to start playback of the VCR, CD player, VCD player, LD player, DVD player, MD deck, DAT deck, tape deck, Blu- ray disc recorder, hard disc recorder, or PSX. X X Press to pause playback or recording of the VCR, CD player, VCD player, LD player, DVD player, MD deck, DAT deck, tape deck, Blu-ray disc recorder, hard disc recorder, or PSX. (Also starts recording with components in recording standby.) Y m/M Press to – search tracks in the forward/ backward direction of the CD player, VCD player, DVD player, LD player, MD deck, Blu-ray disc recorder, hard disc recorder, or PSX. – fast forward/rewind of the VCR, DAT deck, or tape deck. D. TUNING Press to enter direct tuning mode. ANT Press ALT (G) and then press ANT to select the signal to be output from the antenna terminal of the VCR or satellite tuner (TV signal or video signal). CLEAR Press ALT (G) and then press CLEAR to – clear a mistake when you press the incorrect numeric button. – return to continuous playback, etc. of the CD player, DVD player, Blu-ray disc recorder, PSX, or satellite tuner. Name Function Z TUNING +/– Press to scan a station. ./> Press to skip tracks of the VCR, CD player, VCD player, LD player, DVD player, MD deck, DAT deck, tape deck, Blu-ray disc recorder, hard disc recorder, or PSX. 2CH Press to select 2CH STEREO mode. A.F.D. Press to select A.F.D. mode. MOVIE Press to select sound fields (MOVIE). DUAL MONO Press to select the language you want during digital broadcast. AUDIO Press to change the sound to Multiplex, Bilingual or Multi channel TV sound of the TV, VCR, DVD player, satellite tuner, Blu-ray disc recorder, hard disc recorder, or PSX. ANGLE Press to select the viewing angle or change the angles of the DVD player or Blu-ray disc recorder. JUMP/TIME Press to – toggle between the previous and the current channels of the satellite tuner, TV, or Blu-ray disc recorder. – show the time or display the playing time of a disc, etc. of the CD player, MD deck, VCD player, or DVD player. MEMORY Press MEMORY to store a station. SUBTITLE Press ALT (G) and then press SUBTITLE to change the subtitles of the DVD player. ENTER Press ALT (G) and then press ENTER to enter the value after selecting a channel, disc or track using the numeric buttons. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 11 STR-K880/K900 a)The MASTER VOL +, TV VOL +, TV CH + and H buttons have tactile dots. Use the tactile dots as references when operating the receiver. Notes Some functions explained in this section may not work depending on the model. The above explanation is intended to serve as an example only. Therefore, depending on the component, the above operation may not be possible or may operate differently than described. The AUX and 12 buttons on the remote are not available for receiver operation. Name Function Numeric buttons Press ALT (G) and then press the numeric buttons to – preset/tune to preset stations. – select track numbers of the CD player, VCD player, LD player, DVD player, MD deck, DAT deck, or tape deck. Press 0/10 to select track number 10. – select channel numbers of the TV, VCR, satellite tuner, Blu-ray disc recorder, hard disc recorder, or PSX. >10/11 Press ALT (G) and then press >10/11 to select track numbers over 10 of the CD player, VCD player, LD player, MD deck, tape deck, TV, VCR, Blu-ray disc recorder, hard disc recorder, PSX, or satellite tuner. wj Input buttons Press one of the buttons to select the component you want to use. When you press any of the input buttons, the receiver turns on. The buttons are factory assigned to control Sony components as follows. You can program the remote to control non-Sony components following the steps in “Programming the remote”. * The AUX button is not available for receiver operation. Button Assigned Sony component VIDEO1 VCR (VTR mode 3) VIDEO2 VCR (VTR mode 1) VIDEO3 VCR (VTR mode 2) DVD DVD player MD/TAPE MD deck SA-CD/CD Super Audio CD/CD player TUNER Built-in tuner AUX* Not assigned Name Function wk TV ?/1 Press to turn the TV on or off. wl RM SET UP Press to set up the remote. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 12 STR-K880/K900 FACTORY PRESET MODE All preset contents are reset to the default setting. Procedure: 1. While depressing the SPEAKERS (OFF/A/B/A+B) and the MOVIE buttons simultaneously, press the power ?/1 button to turn on the main power. 2. The message “FACTORY” appears and the present contents are reset to the default values. (5 second) AM CHANNEL STEP 9 kHz/10 kHz SELECTION MODE Either the 9 kHz step or 10 kHz step can be selected for the AM channel step. Procedure: 1. Set the FUNCTION to AM. Turn off the main power. 2. While depressing the TUNING MODE button, press the power ?/1 button to turn on the main power. 3. Either the message “9 k STEP” or “10 kSTEP” appears. Select the desired step. FLUORESCENT INDICATOR TUBE TEST MODE All fluorescent segments are tested. When this test is activated, all segments turn on at the same time, then each segment turns on one after another. Procedure: 1. While depressing the TUNING MODE and the DISPLAY buttons simultaneously, press the power ?/1 button to turn on the main power. 2. All segments turn on. 3. Turn the INPUT SELECTOR dial. 4. Turn the INPUT SELECTOR dial once again. 5. Turn the INPUT SELECTOR dial once again. All segments turn off. 6. Every turning of the INPUT SELECTOR dial turns on each segment one after another in the same order. SOUND FIELD CLEAR MODE The preset sound field is cleared when this mode is activated. Use this mode before returning the product to clients upon completion of repair. Procedure: 1. While depressing the 2CH button, press the power ?/1 button to turn on the main power. 2. The message “SF. CLR.” appears and initialization is performed. (5 second) SOFTWARE VERSION DISPLAY MODE The software version is displayed. Procedure: 1. While depressing the SPEAKERS (OFF/A/B/A+B) and the DISPLAY buttons simultaneously, press the power ?/1 button to turn on the main power. 2. The model name, destination and the software version are displayed. (10 second) KEY CHECK MODE Button check Procedure: 1. While depressing the SPEAKERS (OFF/A/B/A+B) and the 2CH buttons simultaneously, press the power ?/1 button to turn on the main power. “REST 13” appears. 2. Every pressing of any button other than ?/1 counts down the buttons. The buttons which are already counted once are not counted again. 3. When all buttons are pressed “REST 00” appears. CHANGE COMMON MODE This mode is command mode changed to AV 1 or AV2. Procedure: 1. While depressing the INPUT MODE button, press the power ?/1 button to turn on the main power. 2. Either the message “C.MODE.AV 1” or “C.MODE.AV 2” appears. (3 second) SHIPMENT MODE All preset contents are reset to the default setting. Procedure: 1. While depressing the SPEAKERS (OFF/A/B/A+B) and the MUSIC buttons simultaneously, press the power ?/1 but- ton to turn on the main power. 2. “CLEARED” appears and switch off the set. PROTECTOR Procedure: 1. While depressing the TUNING MODE and the A.F.D. but- tons simultaneously, press the power ?/1 button to turn on the main power. 2. “ PROT. EVER” appears. (3 second) DECODE AUTO ALL Procedure: 1. While depressing the TUNING MODE and the MOVIE buttons simultaneously, press the power ?/1 button to turn on the main power. 2. “DEC. TEST” appears. (10 second) L SW C R SL S SR SBL SB SBR LFE SP A SP B SLEEP OPT COAX MULTI CH IN 96/24 DIGITALEX PRO LOGIC II x DTS-ES NEO:6 MPEG-2 AAC RDS D.RANGE EQ STEREO MONO D D D D dB kHz mft. MHz MEMORY DIRECT L SW R S SB LFE SP A SP B SLEEP OPT COAX MULTI CH IN 96/24 DIGITALEX PRO LOGIC II x DTS-ES NEO:6 MPEG-2 AAC RDS D.RANGE EQ STEREO MONO D D D D dB kHz mft. MHz MEMORY DIRECT C SL SR SBL SBR SP A SP B SLEEP OPT COAX MULTI CH IN 96/24 DIGITALEX PRO LOGIC II x DTS-ES NEO:6 MPEG-2 AAC RDS D.RANGE EQ STEREO MONO D D D D kHz mft. MHz MEMORY DIRECT SECTION 2 TEST MODE www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 13 STR-K880/K900 VACS CONTROL Procedure: 1. While depressing the TUNING MODE and the MUSIC buttons simultaneously, press the power ?/1 button to turn on the main power. 2. “VACS OFF” appears. (10 second) SWAP ALL MODE Procedure: 1. While depressing the SPEAKERS (OFF/A/B/A+B) and the A.F.D. buttons simultaneously, press the power ?/1 button to turn on the main power. 2. “SWP.ALL” appears. (No change while displayed.) DCAC FACTORY TEST MODE DCAC Factory Test mode have two stages: 1. DCAC DSP Data Line Checking 2. DCAC AUTO CAL MIC board Checking Factory Test System Setup 1. When power off : Press the three buttons TUNING + + MOVIE + ?/1 . “DCAC[]FTM” appears. Afterward, press the TUNING MODE to start DCAC factory test mode. 1.DCAC DSP Data Line Checking After press the TUNING MODE , DCAC Factory test mode will start, below display will show: “DCAC[][][]x” x = 1, 2, 3, 4 If there is error happen, below display will show: “ERR[]SD0x” x = 1 → D1501 or R1530 or C1512 problem x = 2 → D1502 problem x = 3 → D1503 problem x = 4 → D1504 problem 2.DCAC AUTO CAL MIC board Checking Connect front left speaker of the receiver and AUTO CAL microphone. Turn MASTER VOLUME jog, there will be test tone sound output from front left speaker, and the display will change accordingly. “AD[]-[]xxx” xxx = 0 to 255 (depends on loudness of test tone) DSP Data Line Check Start Pass Pass Auto Cal Mic Check END SPK Front Left DCAC MIC Receiver www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 14 STR-K880/K900 SECTION 3 DIAGRAMS For Schematic Diagrams. Note: • All capacitors are in µF unless otherwise noted. (p: pF) 50 WV or less are not indicated except for electrolytics and tantalums. • All resistors are in Ω and 1/4 W or less unless otherwise specified. • % : indicates tolerance. • f : internal component. • 2 : nonflammable resistor. • 5 : fusible resistor. • C : panel designation. • A : B+ Line. • B : B– Line. • Voltages and waveforms are dc with respect to ground un- der no-signal (detuned) conditions. No mark : FM • Voltages are taken with a VOM (Input impedance 10 MΩ). Voltage variations may be noted due to normal production tolerances. • Waveforms are taken with a oscilloscope. • Circled numbers refer to waveforms. • Signal path. F : FM J : ANALOG c : DIGITAL I : VIDEO • Abbreviation AUS : Australian model. CND : Canadian model. E51 : Chilean and Peruvian models. SP : Singapore model. SP6 : Singapore and Malaysia models. For Printed Wiring Boards. Note: • X : parts extracted from the component side. • a : Through hole. • f : internal component. • : Pattern from the side which enables seeing. • Indication of transistor. Caution: Pattern face side: Parts on the pattern face side seen from (Side B) the pattern face are indicated. Parts face side: Parts on the parts face side seen from (Side A) the parts face are indicated. Note: The components identi- fied by mark 0 or dot- ted line with mark 0 are critical for safety. Replace only with part number specified. Note: Les composants identifiés par une marque 0 sont cri- tiques pour la sécurité. Ne les remplacer que par une piéce portant le numéro spécifié. C B These are omitted. E Q B These are omitted. C E THIS NOTE IS COMMON FOR PRINTED WIRING BOARDS AND SCHEMATIC DIAGRAMS. (In addition to this, the necessary note is printed in each block.) Ver. 1.1 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 15 15 STR-K880/K900 STR-K880/K900 • Waveforms – DIGITAL Board – 1 IC1501 9 (MCLK1) 1 V/DIV, 40 ns/DIV 72 ns 3.4 Vp-p 2 IC1101 id (X1) 1 V/DIV, 20 ns/DIV 41.6 ns 4.2 Vp-p 3 IC1301 ws (XIN) 1 V/DIV, 40 ns/DIV 81 ns 4.4 Vp-p • Circuit Boards Location DIGITAL board MAIN board POWER board ADCC board HEADPHONE board STANDBY board AC SELECT board (E51 only) SPEAKER board SPEAKER B board HDMI board VIDEO board DISPLAY board VIDEO 3 board w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 16 16 STR-K880/K900 STR-K880/K900 3-1. BLOCK DIAGRAM – MAIN SECTION – AUDIO IN AUDIO IN AUDIO IN PROCESSOR INCL 26 88 OUT L INBL 24 INGL 34 85 OUT SL 86 OUTC 81 OUT SW DATA 60 CLK 59 59 VOL_CLK SDA SCL 60 VOL DATA LATCH SYSTEM CONTROL IC1101(1/2) IC203 VIDEO AMP IC1601,1602 S/P CONV. IC807 +5V REG DVD IN COAXIAL VIDEO 2 IN J1301 3 5 6 2 J298(1/2) IC1303 DIGITAL AUDIO I/F RECEIVER IC1301 L DISPLAY /POWER SECTION DIN2 5 DO 35 DI 36 CLK 38 CE 37 ERROR 34 XSTATE 17 XMODE 48 13 CK OUT 20 XMCK 14 BCK 15 LRCK 16 DATAO IC1303 X1301 12.288MHz AUDIO DSP IC1501 KFSI0 SYSCLK LRCK BCK DOUT 22 16 13 14 15 SDI2 30 HCLK 34 HCS 36 HACN 32 PM 113 XRST 2 23 SDO1 24 SDO2 25 SDO3 BCKI2 29 LRCKI2 28 LRCKI1 15 BCKI1 17 IC1502 SRAM AUDIO CODEC IC1452 IC1403 AD CONVERTER IC1401 SCKI 38 RST 37 ML 36 MC 35 MDI 34 MDO 33 10 VOUT5 BCK 40 LRCK 41 DATA3 47 DATA1 45 26 SDO4 DATA4 31 DATA2 46 14 VOUT1 12 VOUT3 11 VOUT4 ANALOG SOUND 44 ROUTAL SL AOUTL 41 INCL 49 52 51 56 SL C 83 OUTSBL SBL INCSL INCC INCSW A 98 97 95 96 99 100 94 1 6 13 89 DO DI CLK CE ERROR XSTATE CKSEL1 DATA0 3 BST SW4 V1 D595_LAT 20 HCLK 4 HCS 5 HACN 7 PM 92 BST SEL 6 XRST 10 PCM1608/1800_RST 12 PCM1608_ML 13 PCM1608_MC 14 PCM1608_MDI 15 PCM1608_MDO 5 6 29 30 RELAY DRIVE Q560 J404 (1/2) VIDEO 1 IN J402 SA-CD/CD VIDEO 2 AUDIO MD/TAPE DVD OPTICAL IN IC1351 DIN0 3 DIN1 4 VIDEO 1 IN OPTICAL IN IC1354 22 21 XIN XOUT 12 9 93 XMODE CKSEL1 47 GP9 68 HD OUT 35 HD IN 33 2 GP9 18 HD OUT 19 HD IN MCLK1 MCLK2 X1502 13.9MHz 14 SCK OUT 1 LIN 6 RST 20 BCKO 19 LRCKO 18 SDI1 24 AUDIO GP8 69 EXLOCK 59 INIL 38 TN1 TUNER PACK FM 75 W COAXIAL AM R-CH ST-DI ST-DO CLK CE STEREO TUNED MUTING FM AM R CH L CH TUNER +10V 10V DO 73 SLATCH 74 TUNER-DATA 17 T.SERIAL CLK 16 STEREO 76 TUNED 75 MUTE 78 OPTICAL DIGITAL D1301 IC401 SDA SCL EEPROM IC1131 IC402 WOOFER AMP SW RY 70 IN INFL 32 INDL 28 INEL 30 J403 (1/2) VIDEO 1 J404 (2/2) AUDIO OUT 46 ROUTBL MD/TAPE J402 (2/2) OUT RY560 AUDIO OUT J309 SUB WOOFER 5 7 14 86 SW1 D595_DATA 88 D595_OE 4 SW3 10 87 SW2 D595_CLK VIDEO IN J201 (1/2) J200 (1/2) VIDEO 1 VIDEO IN VIDEO 2 VIDEO IN DVD 9 V3 VIDEO J298 (2/2) VIDEO 3 IN/ PORTABLE AV IN 5 V2 3 DVD 1 M.OUT MONITOR + V J201(2/2) VIDEO OUT 15 V.OUT 16 VCC VIDEO 1 J200(2/2) VIDEO OUT IC804 -5V REG - V 8 VEE IC1503 SELECTOR 1 6 5 56 2 A B BST S Y 3 1 IC1405 5 7 IC1404 3 1 IC1404 5 7 16 VOUT7 54 INCSB IC1406 5 7 J401 SUB WOOFER CENTER FRONT SURROUND ANTENNA MULTI CH IN INDL 12 INDL 17 INDL 13 INDL 10 J301 (1/2) Y PR/CR/R-Y PB/CB/B-Y Y DVD IN VIDEO 2 IN COMPONENT VIDEO PR/CR/R-Y PB/CB/B-Y CH1 IN2 3 CH2 IN2 9 CH3 IN2 14 CH1 IN3 5 CH2 IN3 11 CH3 IN3 12 SW1 2 SW2 4 CH1 OUT 22 CH2 OUT 20 CH3 OUT 18 Y PR/CR /R-Y PB/CB /B-Y MONITOR OUT CONPONENT VIDEO J301 (2/2) VIDEO AMP IC304 (Page 17) FL_DATA FL_CLK B DISPLAY /POWER SECTION (Page 17) CN5001 CN5002 CN5003 DVD IN HDMI HDMI VIDEO 2 IN MONITOR OUT OEB 42 2,3,5, 6,8,9, 11,12, 14,15, 80 62-64, 67,68, 70,71, 73,74, 76,77 25,26, 28,29, 31,32, 34,35, 38-40 S1 21 IC5004 INPUT DET 1 5 7 3 IC5005 INPUT SELECT 3 1 4 6 IC5006 +5.8V REG IC5003 +3.3V REG +3.3V +8V 2 4 1 3 IC5002 +5V REG IC5001 HDMI SELECT 5 4 1 1 VIDEO 3 IN/ PORTABLE AV IN 57 ADCC_DSP_INT D1501-1504 • Signal Path : FM : ANALOG : DIGITAL : VIDEO • R-CH is omitted due to same as L-CH. w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 17 17 STR-K880/K900 STR-K880/K900 3-2. BLOCK DIAGRAM – DISPLAY/POWER SECTION – • R-CH is omitted due to same as L-CH. IN2 8 12 +V OUT2 POWER AMP IC701 POWER AMP IC601 9 NF2 LIMITER Q701,702 11 -V OUT2 IN2 12 +V OUT2 9 NF2 11 -V OUT2 BOOSTER Q703 BOOSTER Q704 CURRENT DETECT Q705,706 AF POWER PROTECT Q740 LIMITER Q651,652 BOOSTER Q653 BOOSTER Q654 CURRENT DETECT Q655,656 IN2 8 12 +V OUT2 POWER AMP IC501 9 NF2 LIMITER Q501,502 11 -V OUT2 BOOSTER Q503 BOOSTER Q504 CURRENT DETECT Q505,506 2 +V OUT1 5 NF1 LIMITER Q571,572 3 -V OUT1 BOOSTER Q533 BOOSTER Q534 CURRENT DETECT Q535,536 D721 PROTECT SWITCH Q722,723,725 RELAY DRIVE Q790 RY791 RELAY DRIVE Q710 RY701 D1110 RELAY DRIVE Q610 RY601 RY600 D1108 RELAY DRIVE Q800 RELAY DRIVE Q550 RY501 D1107 D1111 L R SR SL C R-CH L R R-CH R-CH R-CH PHONES TM601 TM602 61 PROTECTOR 62 HP RY 66 FRONT RY 69 REAR RY 68 C/SB RY 67 SP_B_RY RV102 ENCODER 3 1 VOL_ENC(B) 64 VOL_ENC(A) 65 POWER KEY 56 ?/1 S100 77 RSTX 48 STOP 54 SIRCS 72 BRIGEABLE RY 63 FUSE DETECT REMOTE CONTROL RECEIVER 1 IC102 D910-913 AC IN T902 RY901 D915 F901 D914 RELAY DRIVE Q901 D920-923 23 VCC5 84 VCC3 -7V REG 3 2 +7V REG 1 3 AUDIO +7V IC801 IC802 POWER RY 58 RELAY +B D805-808 82 83 X0 X1 X1101 24MHz F1 F2 L SL SL C A IN1 6 SBL J791 FLUORESCENT INDICATOR TUBE FL101 FL_DATA FL_CLK 9 FL_LAT 7 DIN 8 CLK 9 STB 14 29 SEG1-16 42 31 GRID1-12 F1 F2 FL DRIVE IC100 ADCC 38 S108-111,115 FUNCTION KEY A/D1 39 FUNCTION KEY A/D2 40 S101-107 SYSTEM CONTROL IC1101(2/2) • Signal Path : FM AF POWER PROTECT Q640 AF POWER PROTECT Q540 AF POWER PROTECT Q580 IC691 2 1 FRONT A FRONT B SURROUND IC691 5 7 55 HP DETECT BUFFER IC101 35 AVCC +3.3V REG 3 1 IC1904 AUDIO -7V +10V REG 3 1 TUNER +10V IC1902 +3.3V REG 3 1 TUNER +3.3V IC1071 RY801 T901 Q921 AC DET 1 2 IC1111 D802 R803 +B -B -B SWITCH Q691,692 RELAY DRIVE Q809 VOLTAGE SELECT S901 -20V REG Q801 FL101 -20V POWER AMP -B +5V REG 3 1 IC1031 +5V +2.5V REG 5 +2.5V +3.3V REG 2 4 IC1901 +3.3V +5V REG 3 1 IC1001 AUDIO +5V SPEAKERS IMPEDANCE USE 6-16Ω MASTER VOLUME RV101 ENCODER 3 1 ENC_B 32 ENC_A 31 INPUT SELECTOR 8 RESET 5 1 IC2000 AMP +3.3V (STBY) MAIN SECTION TM501 K880 CENTER SB SURROUND BACK (Page 16) B MAIN SECTION (Page 16) AUTO CAL MIC J2000 RY802 RY803 AEP, UK CND E51 EXCEPT CND EXCEPT E51 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 18 18 STR-K880/K900 STR-K880/K900 3-3. PRINTED WIRING BOARD – DIGITAL BOARD (SIDE A) – :Uses unleaded solder. • See page 15 for Circuit Boards Location. IC1301 IC1303 IC1452 IC1501 IC1502 IC1602 IC1601 IC1503 IC1101 IC1131 IC1406 IC1405 IC1404 IC1403 IC1401 IC1111 AEP,UK EXCEPT AEP,UK EXCEPT AEP,UK AEP,UK 1 2 A B C D E 3 4 5 6 7 • Semiconductor Location Ref. No. Location D1001 B-6 D1301 C-2 D1302 C-1 D1501 D-6 D1502 D-6 IC1101 D-5 IC1111 C-6 IC1131 E-5 IC1301 B-2 IC1303 C-2 IC1401 E-2 IC1403 E-3 IC1404 E-3 IC1405 E-4 IC1406 E-5 IC1452 D-2 IC1501 D-3 IC1502 C-3 IC1503 D-4 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 19 19 STR-K880/K900 STR-K880/K900 3-4. PRINTED WIRING BOARD – DIGITAL BOARD (SIDE B) – :Uses unleaded solder. • See page 15 for Circuit Boards Location. MAIN BOARD CNP911 (Page 25) MAIN BOARD CNP913 (Page 25) A B DISPLAY BOARD CNS100 (Page 29) C MAIN BOARD CNP500 (Page 25) G MAIN BOARD CNP501 (Page 25) H STANDBY BOARD CNP903 (Page 31) D MAIN BOARD CNP912 (Page 25) E VIDEO BOARD CNS203 (Page 37) F IC1031 IC1901 IC1904 IC1071 IC1001 IC1902 IC1354 IC1351 1 1 7 5 1 1 1 2 3 3 3 4 5 for FLASH PROGRAMMING 1 6 23 7 10 AEP,UK AEP,UK AEP,UK TUNER UNIT VIDEO 1 IN VIDEO 2 IN DVD IN COAXIAL OPTICAL DIGITAL K880 17 16 1 3 3 3 3 1 1 3 1 1 1 2 A B C D E 3 4 5 6 7 8 • Semiconductor Location Ref. No. Location D1003 D-6 D1004 D-6 D1107 C-3 D1108 C-3 D1110 C-3 D1111 C-3 D1503 D-6 D1504 D-6 IC1001 E-6 IC1031 B-1 IC1071 B-4 IC1351 C-7 IC1354 B-7 IC1601 C-5 IC1602 C-5 IC1901 B-2 IC1902 A-4 IC1904 B-3 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 20 20 STR-K880/K900 STR-K880/K900 3-5. SCHEMATIC DIAGRAM – DIGITAL BOARD (1/5) – • See page 15 for Waveform. • See page 41 for IC Block Diagram. C1303 C1305 R1318 R1313 R1314 R1355 R1356 R1357 R1358 R1359 R1354 R1351 X1301 R1310 C1313 R1316 R1315 C1004 R1312 C1914 JR1202 C1005 C1306 R1301 R1306 IC1354 IC1351 C1354 C1351 C1357 C1355 C1252 C1253 C1308 TN1 C1064 JR1005 R1302 JR1302 JR1303 R1323 C1362 TP1003 FB1302 R1305 R1308 C1312 R1319 C1310 R1311 R1360 FB1305 TP1004 R1307 C1314 FB1306 C1359 C1358 C1361 R1261 R1260 R1252 R1251 JR1020 R1321 C1315 C1302 C1301 C1309 C1360 JR1511 C1304 R1304 R1303 C1913 C1063 IC1071 D1302 IC1902 CNS508 J1301 JR1207 D1003 D1004 IC1301 C1251 JR1019 D1301 IC1303 R1362 R1309 100 100 0 TORX147L TORX147L 0.1 0.1 0.1 0.1 10k 100 10k 75 1k 22k 560k 100 12.288MHz 1M 100p 100 100 0.1 100 47 16V 0.1 47 16V 5.6k 22 1p 22 25V 0.1 0.1 0.1 47 16V 0 4.7k 0 0 10k 0.01 680 100 0.1 0 18p 100 100 100 0.1 1000 6.3V 0.1 0.1 1k 1k 39k 39k 0 0 0.1 0.01 0.1 18p 47p 0.01 100 33k 0.1 0.1 TA78033LS 1SS355-TE-17 TA7809LS 0 1SS367-T3SONY 1SS367-T3SONY LC89056W-E 0.1 0.1 1SS355TE-17 TC7WU04F(TE12R) 100 100 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 21 21 STR-K880/K900 STR-K880/K900 3-6. SCHEMATIC DIAGRAM – DIGITAL BOARD (2/5) – • See page 15 for Waveform. • See page 42 for IC Block Diagram. R1502 R1503 R1504 R1505 R1506 R1507 R1508 R1509 R1511 TP1005 TP1008 TP1009 TP1010 TP1011 TP1012 TP1015 C1516 C1518 R1512 R1515 R1514 R1555 R1541 R1574 R1573 R1572 R1571 R1570 X1502 R1523 TP1018 R1557 R1556 C1525 FB1502 FB1501 C1501 C1503 C1504 C1505 C1506 C1508 C1513 C1514 C1520 C1515 C1517 C1509 C1511 C1502 C1521 C1522 JR1008 C1507 C1510 R1513 R1530 C1519 IC1501 FB1503 D1501 D1502 D1503 D1504 IC1502 JR1016 IC1503 RB1504 RB1502 RB1501 RB1506 RB1503 RB1508 RB1507 RB1500 R1501 R1510 100 220 100 100 100 100 100 100 100 0.1 0.1 1k 1M 10k 220 220 10k 10k 10k 10k 10k 13.9MHz 220 220 100 470 10V 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 470 10V 470 10V 0.1 0.1 0.1 27p 27p 0 0.1 0.1 10k 100k 0.1 CXD9718BQ 1SS367-T3SONY 1SS367-T3SONY 1SS367-T3SONY 1SS367-T3SONY IS61WV6416BLL -12TLI 0 TC7WH157FU (TE12R) 100 100 100 100 100 100 100 100 100 100 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 22 22 STR-K880/K900 STR-K880/K900 3-7. SCHEMATIC DIAGRAM – DIGITAL BOARD (3/5) – • See page 41, 43 for IC Block Diagrams. C1001 FB1405 R1414 R1454 R1424 R1463 R1434 R1444 R1483 C1460 FB1452 FB1453 C1438 C1428 C1458 C1418 C1448 R1486 R1446 R1436 R1466 R1426 R1416 C1487 C1547 C1566 C1569 C1568 C1567 C1557 C1402 C1403 C1407 CNS501 R1474 R1403 R1445 R1435 R1464 R1425 R1455 R1490 R1491 R1492 R1493 R1494 R1495 R1407 C1413 C1411 C1453 C1451 C1423 C1422 C1463 C1462 C1433 C1432 C1442 C1441 C1483 C1481 C1450 C1454 C1494 C1405 C1408 C1401 C1409 R1402 IC1452 IC1001 C1002 R1473 C1473 C1472 IC1403 IC1404 IC1405 IC1406 IC1401 C1457 R1461 R1470 C1541 C1544 C1543 C1540 R1472 R1475 R1420 C1478 C1491 R1401 C1406 R1476 C1468 R1484 C1404 R1471 C1545 R1460 C1542 R1421 470 10V 6.8k 6.8k 6.8k 6.8k 6.8k 6.8k 6.8k 10 50V 10 50V 10 50V 10 50V 10 50V 10 50V 1k 1k 1k 1k 1k 1k 0.0022 0.0022 0.0022 0.0022 0.0022 0.0022 0.0022 47 16V 10 50V 4.7 50V 15P 10k 10k 0 0 0 0 0 6.8k 6.8k 6.8k 6.8k 6.8k 6.8k 100 330p 680p 330p 680p 330p 680p 330p 680p 330p 680p 330p 680p 680p 330p 0.1 0.1 0.1 470p 470p 0.1 0.1 2.2k PCM1609APT TA7805S 0.1 25V 8.2k 0.1 0.1 NJM4565M(TE2) NJM4565M(TE2) NJM4565M(TE2) NJM4565M(TE2) PCM1800E12K 10 50V 0.1 8.2k 10K 10K 10K 10K 0.1 0.1 0.1 10 50V 10 50V 1k 4.7 50V 1k 10 50V 0 0.1 0.1 10K 0.1 10K 6.8k w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 23 23 STR-K880/K900 STR-K880/K900 3-8. SCHEMATIC DIAGRAM – DIGITAL BOARD (4/5) – • See page 42 for IC Block Diagrams. * * R1181 R1179 R1180 R1182 R1189 R1190 R1088 C1906 C1908 R1201 R1039 FB1308 C1104 C1105 R1183 R1184 R1105 R1186 IC1601 IC1602 C2218 CNP503 CNP504 CNP505 C1022 IC1031 C1032 C1137 C1108 FB1101 IC1901 R1065 R1066 R1067 R1068 C1138 C1140 R1061 R1062 R1063 FB2034 C2216 C2217 R1010 R1011 R1012 R1013 R1014 R1015 R1016 R1127 R1187 JR1015 C1602 C1601 R1116 R1130 R1175 C1021 C1031 D1001 IC1904 CNS509 CNS505 R1193 R1124 D1108 D1107 D1110 D1111 C1905 IC1111 C1107 R1128 10k 10k 10k 10k 10k 10k 10k 470 10V 470 10V 22k 10k 0UH 0 0 10k 10k 10k 10k SN74HC595ANSR SN74HC595ANSR 47 16V 5P 7P 10P 470 10V BA50BC0T 470 10V 0.01 0.1 SI-3004KWF 100 100 100 100 0.1 0.1 100 100 100 0UH 0.1 0.1 100 100 100 100 100 100 100 100 10k 0 100p 0.01 100 10k 100 0.1 0.1 1SR154-400TE-25 BA033BCOT 17P 23P 100 1SS355TE-17 1SS355TE-17 1SS355TE-17 1SS355TE-17 0.1 S-80929CNMC -G8ZT2G 0.1 100 AEP, UK, SP, SP6 Ver. 1.1 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 24 24 STR-K880/K900 STR-K880/K900 3-9. SCHEMATIC DIAGRAM – DIGITAL BOARD (5/5) – • See page 15 for Waveform. • See page 46 for IC Pin Function Description. * R1136 R1134 C1102 R1129 R1119 R1118 R1117 R1110 R1109 R1107 R1140 R1143 R1149 R1150 R1153 R1154 R1155 R1192 C1131 C1132 R1097 C1130 C1100 R1152 R1151 R1077 R1078 R1058 R1041 R1044 R1042 R1636 R1635 R1122 R1123 R1164 C1124 C1123 C1122 R1114 R1524 C1144 C1145 R1185 R1188 C1172 C1171 R1084 R1125 R1126 CNS504 R1156 R1157 C1139 C1103 C1121 R1160 R1161 IC1131 R1073 C1604 C1620 C1605 C1299 R1120 C1119 R1112 R1083 R1059 R1035 R1108 R1111 R1113 R1115 C1142 R1072 C1120 C1129 C1255 C1254 C1495 R1096 C1149 R1135 R1137 R1049 R1162 R1144 R1142 R1106 R1082 R1081 JR1104 CNS502 X1101 R1121 R1076 R1159 R1103 C1146 R1095 R1094 C1118 R1194 IC1101 100 100 0.1 100 1k 1k 1k 2.2k 2.2k 2.2k 100 100 100 100 100 100 100 10k 0.01 0.01 100k 0.01 0.1 100 100 100 100 220 100 100 100 2.2k 2.2k 100 100 0 0.1 0.1 0.1 2.2k 0 0.01 0.01 10k 10k 0.01 0.01 100 100 100 9P 0 0 0.1 47 16V 0.1 100 100 BR24L16 3.3k 0.1 0.1 0.1 0.1 1k 0.1 100 10k 220 2.2k 2.2k 2.2k 100 100 0.1 3.3k 0.01 0.01 220p 220p 220p 10k 220p 100 100 10k 100 100 100 100 100 100 0 10P 24MHz 100 100 3.3k 0 0.01 10k 10k 0.1 MB90488BPF-G -175E1 SP, SP6 * Ver. 1.1 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 25 25 STR-K880/K900 STR-K880/K900 3-10. PRINTED WIRING BOARD – MAIN BOARD – • Semiconductor Location Ref. No. Location D505 G-5 D529 F-5 D540 G-4 D560 D-8 D580 G-2 D585 G-3 D605 G-13 D610 D-9 D640 G-9 D665 G-10 D680 G-11 D690 E-9 D691 E-9 D692 E-9 D693 E-9 D705 G-7 D710 D-10 Ref. No. Location D721 F-11 D722 F-11 D729 F-6 D732 F-12 D740 G-6 D749 F-6 D750 G-10 D765 G-11 D791 F-14 D801 E-14 D802 D-14 D804 F-13 D805 E-14 D806 E-14 D807 D-14 D808 D-14 D841 F-2 Ref. No. Location D896 E-7 IC401 E-4 IC402 F-4 IC501 F-4 IC601 F-8 IC691 E-8 IC701 F-6 IC801 D-7 IC802 E-7 Q501 G-4 Q502 H-5 Q503 H-5 Q504 H-6 Q505 G-6 Q506 G-5 Ref. No. Location Q533 H-3 Q534 H-4 Q535 G-4 Q536 G-3 Q540 G-4 Q560 D-8 Q571 G-2 Q572 H-3 Q580 G-2 Q601 H-12 Q602 H-12 Q603 H-12 Q604 H-13 Q605 G-13 Q606 G-13 Q610 D-9 Q640 G-8 Ref. No. Location Q651 G-8 Q652 H-9 Q653 H-8 Q654 H-9 Q655 G-9 Q656 G-10 Q680 G-11 Q691 F-10 Q692 E-9 Q693 E-9 Q694 E-9 Q695 E-10 Q701 G-6 Q702 H-7 Q703 H-6 Q704 H-7 Q705 G-8 Ref. No. Location Q706 G-7 Q710 D-10 Q722 F-12 Q723 F-12 Q725 F-12 Q740 G-6 Q750 G-10 Q751 G-10 Q752 H-11 Q753 H-10 Q754 H-11 Q755 G-11 Q756 G-12 Q790 F-14 Q793 F-12 Q795 F-11 Q801 F-13 :Uses unleaded solder. • See page 15 for Circuit Boards Location. IC401 IC801 IC802 IC402 IC691 IC501 IC701 IC601 AEP,UK, SP,SP6,AUS AEP,UK,SP,SP6,AUS AEP,UK,SP, SP6,AUS AEP,UK,SP, SP6,AUS 880 880 880 880 880 880 880 L R L R SA-CD/CD MD/TAPE IN OUT L R L R IN AUDIO IN DVD AUDIO IN VIDEO 2 AUDIO IN AUDIO OUT L R L R L R VIDEO 1 CENTER L R L R AUDIO OUT SUB WOOFER SUB WOOFER MULTI CH IN - + - + - + L L R R FRONT A FRONT SURROUND SURROUND - + SPEAKERS IMPEDANCE USE 6-16 Ω I ADCC BOARD CNP2000 (Page 35) H DIGITAL BOARD CNS501 (Page 19) J VIDEO 3 BOARD CN201 (Page 35) L SPEAKER B BOARD CNP600 (Page 34) K VIDEO BOARD CNP203 (Page 37) G DIGITAL BOARD CNS502 (Page 19) U SPEAKER BOARD CNP503 (Page 32) T SPEAKER BOARD CNP503 (Page 32) M SPEAKER BOARD CNP503 (Page 32) N STANDBY BOARD CNP801 (Page 31) SPEAKER B BOARD CNP808 (Page 34) O SPEAKER B BOARD CNP601 (Page 34) P DIGITAL BOARD CNP505 (Page 19) E POWER TRANSFORMER T901 (Page 31) Q SPEAKER BOARD CN502 (Page 32) R DIGITAL BOARD CNP504 (Page 19) A HEADPHONE BOARD CNP791 (Page 37) S DIGITAL BOARD CNP503 (Page 19) B 880 1 1 1 1 1 1 1 1 1 4 3 6 4 E C B 4 5 4 5 5 E E E E E E E E E E 5 1 1 1 1 1 4 3 3 3 4 8 E E E 1 1 30 31 50 51 80 81 100 1 15 1 15 1 E E E E E E E E E E E E E E E C B E C B E C B E C B E C B E C B E C B E C B E E E E E C B E C B E C B E E E E E E E E E C B E E E E 15 4 8 5 10 1 2 A B C D E F G H I 3 4 5 6 7 8 9 10 11 12 13 14 15 TM601 Ver. 1.1 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 26 26 STR-K880/K900 STR-K880/K900 3-11. SCHEMATIC DIAGRAM – MAIN BOARD (1/3) – AEP, UK, SP, SP6, AUS AEP, UK, SP, SP6, AUS R407 R457 R406 R456 R408 R458 C408 C458 R405 R455 R404 R454 R402 R452 R436 R435 R434 R433 R432 R431 C493 C485 C495 C488 C484 R459 R409 C459 C409 C468 C469 C463 C453 R475 R476 IC401 CC02 CC09 CC04 CC05 CC07 CC06 CC08 CC52 CC59 CC54 CC55 CC57 CC56 CC58 CC32 CC31 CC33 CC34 CC35 CC36 CNP503 WP100 CNP501 C702 R428 R429 CNP500 C464 C481 C492 J402 C403 J403 J404 J401 C762 C445 C490 1k 1k 1k 1k 1k 1k 4.7 50V 4.7 50V 1k 1k 1k 1k 1k 1k 1k 1k 1k 1k 1k 1k 10 50V 10 50V 10 50V 0.1 10 50V 1k 1k 4.7 50V 4.7 50V 100p 100p 220p 220p 10k 10k BD3451KS 100P 100P 100P 100P 100P 100P 100P 100P 100P 100P 100P 100P 100P 100P 220P 220P 220P 220P 220P 220P 3P SYSTEM GND 15P 10 50V 1k 1k 10P 0.1 10 50V 10 50V 0.1 10 50V 0.1 10 50V AEP, UK, SP, SP6, AUS AEP, UK, SP, SP6, AUS AEP, UK, SP, SP6, AUS AEP, UK, SP, SP6, AUS Ver. 1.1 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 27 27 STR-K880/K900 STR-K880/K900 3-12. SCHEMATIC DIAGRAM – MAIN BOARD (2/3) – • See page 43 for IC Block Diagrams. AEP, UK, SP, SP6, AUS AEP, UK, SP, SP6, AUS AEP, UK, SP, SP6, AUS AEP, UK, SP, SP6, AUS R737 C722 D721 R753 R703 C755 C705 L701 R669 C670 L651 R735 C721 R736 L601 R620 C619 R623 R701 R751 L751 R769 C770 R603 R653 R654 C605 C655 R651 R601 R731 C706 C756 C656 C606 R604 C707 C757 C657 C607 C503 R501 R505 R503 R520 C519 C540 C640 C750 D750 C701 C751 C651 C601 R791 R674 R625 R624 R775 R778 R525 R524 R744 R743 R718 R618 R714 R715 R665 R664 R614 R615 R765 R514 R515 C680 R695 R698 C732 C691 R793 C642 C681 C752 C541 R780 D690 R690 R634 R631 C740 C742 R741 C741 C506 R553 WP02 C791 WP101 R671 R621 R771 R521 D693 JW501 JW502 JW504 R540 R557 R640 R677 R750 R757 Q692 R680 R657 R694 R691 R648 R681 R758 R546 R699 R740 R747 R748 R697 R700 R705 R689 CNP806 CN808 CN807 CN792 RY601 RY701 RY791 WP102 R702 R752 C753 C703 R704 R754 C743 R652 R602 C653 C603 R733 C733 R732 R693 C507 R502 C501 C610 R713 R711 R710 R663 R725 C711 R717 R723 R673 C661 R667 R638 C717 R719 C720 C660 R660 R661 R672 R668 R622 R617 C611 R611 R610 R613 R763 C760 R761 R760 R764 R772 C761 R773 R767 R522 R511 R510 C510 R513 C710 R722 R721 D722 R794 CC11 RR11 RR13 CC15 CC17 RR14 CC13 RR12 R768 WP03 R573 C511 R517 R526 R724 C744 IC601 IC701 IC501 C704 C754 C654 C604 C565 C505 JW505 JW503 C566 R562 C567 R561 C561 C553 C554 R554 C504 R696 IC691 R706 D692 Q695 Q694 Q693 Q691 D691 R692 Q501 Q571 Q502 Q572 C570 R570 R571 R574 Q503 Q534 R576 R575 C576 R531 C577 Q506 Q536 Q535 C539 R530 R516 R766 R616 R666 R716 Q701 Q702 Q652 Q602 Q752 Q751 Q601 Q651 Q703 Q704 Q654 Q653 Q603 Q604 Q754 Q753 Q504 Q533 Q505 Q756 Q755 Q606 Q605 Q656 Q655 Q706 Q705 D705 D665 D605 D765 D505 D585 Q580 D580 Q540 D540 D529 Q750 Q680 Q640 Q740 D740 R746 R745 D729 R739 C729 R729 C716 C669 C666 D640 R676 R675 D680 C621 C620 C767 D749 C749 R749 R755 R756 R759 C766 C517 C516 R840 C842 D841 R844 R655 R656 R556 R555 R586 R585 R537 C531 R523 R580 R588 R534 R572 R535 C581 R587 C580 D791 Q790 Q710 D710 Q610 D610 TM601 R734 Q793 Q795 Q725 D732 Q723 Q722 R792 R529 C529 R539 2.2k 2.2k 2.2k 2.2k 2.2k 2.2k 220 39k 10 50V 1SS133T 33p 500V 33p 500V 4.7k 220p 6.8k 220 10V 1k 4.7k 220p 47k 1k 1k 4.7k 220p 68k 33p 500V 33p 500V 1k 1k 2.2k 100p 100p 100p 100p 68k 100p 100p 100p 100p 100 10V 1k 68k 4.7k 220p 10 50V 10 50V 10 50V 1SS133T-72 4.7 50V 4.7 50V 4.7 50V 4.7 50V 2.2k 15k 68k 15k 68k 15k 68k 15k 15k 15k 4.7 4.7 33 33 33 33 33 33 33 33 33 10 50V 10k 10k 10 100V 0.1 82 0.01 0.01 0.01 0.01 10k HZS30-1LTA 220k 82 2.2k 10 50V 0.01 15k 2.2 100V 100p 220 10V 6.2k 6.2k 6.2k 6.2k HZS30-1LTA 22k 15k 22k 15k 22k 15k DTA124ESATP 22k 15k 10k 15k 15k 15k 15k 470k 22k 15k 15k 47k 10k 470k 10k 3P 2P 4P 4P SYSTEM GND 68k 68k 100 10V 100 10V 68k 68k 2.2 100V 68k 68k 100 10V 100 10V 1 10 100V 1 10k 100p 68k 4.7 50V 47 25V 560 82k 2.2k 560 68k 0.022 10 47k 47k 0.022 10 68k 47p 4.7k 220p 47 25V 2.2k 82k 1.5k 4.7 1.5k 10 0.022 82k 2.2k 560 560 47 25V 82k 2.2k 33 1.5k 0.022 47k 10 1.5k 82k 2.2k 47 25V 560 47 25V 1.5k 6.2k 1SS133T 680 1W 0.01 10 10 0.01 0.01 10 0.01 10 4.7 47k 0.022 10 15k 2.2 100V 3p 500V 3p 500V 3p 500V 3p 500V 33p 500V 33p 500V 100p 68k 100p 1k 4.7 50V 100 10V 5p 500V 68k 5p 500V 47k NJM4565D 220 2W ISS133T -72 2SA1115 TP-EF 2SC1815GR-TPE2 2SC1815GR-TPE2 2SC1815 GR-TPE2 ISS133T-72 330 2SA1115TP-EF 2SA1115TP-EF 2SC3623ATP-LK 2SC3623ATP-LK 47 25V 2.2k 82k 33 MN2488-OPY-MK MN2488-OPY-MK 560 33 47p 500V 6.2k 47p 500V 2SA1038S-RSE-TP 2SA1038S-RSE-TP 2SA1038S-RSE-TP 220p 4.7k 2SA1115TP-EF 2SC3623ATP-LK 2SC3623ATP-LK 2SC3623ATP-LK 2SC3623ATP-LK 2SA1115 TP-EF 2SA1115TP-EF 2SA1115TP-EF MN2488 -OPY-MK MP1620 -OPY-MK MP1620 -OPY-MK MN2488 -OPY-MK MN2488 -OPY-MK MP1620 -OPY-MK MP1620 -OPY-MK MN2488 -OPY-MK MP1620-OPY-MK MP1620-OPY-MK 2SA1038S -RSE-TP 2SA1038S -RSE-TP 2SA1038S -RSE-TP 2SA1038S -RSE-TP 2SA1038S -RSE-TP 2SA1038S -RSE-TP 2SA1038S -RSE-TP 2SA1038S -RSE-TP 2SA1038S -RSE-TP 1SS133T-72 1SS133T-72 1SS133T-72 1SS133T-72 1SS133T-72 1SS133T-72 2SC1815GR-TPE2 1SS133T-72 2SC1815 GR-TPE2 1SS133T-72 1SS133T-72 2SC1815 GR-TPE2 2SC1815 GR-TPE2 2SC1815 GR-TPE2 2SC1815GR-TPE2 1SS133T-72 47k 4.7k 1SS133T-72 100k 0.01 10k 47p 500V 47p 500V 47p 500V 1SS133T-72 47k 4.7k 1SS133T-72 47p 500V 47p 500V 47p 500V 1SS133T-72 0.01 10k 4.7k 47k 100k 47p 500V 47p 500V 47p 500V 6.8k 47 25V MTZJ-3.0 22k 4.7k 47k 47k 4.7k 47k 4.7k 10 0.022 47k 22k 15k 15k 1.5k 68k 0.01 15k 10 50V 1SS133T -72 2SC1740S-QRT 2SC1740S-QRT 1SS133T -72 2SC1740S-QRT 1SS133T-72 82 2SC1740S-QRT 2SA1038S-RSE-TP 2SA1038S -RSE-TP 1SS133T-72 2SC1740S -QRT 2SC1841TP -PAFAEA 680 1W 10k 0.01 100k Ver. 1.1 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 28 28 STR-K880/K900 STR-K880/K900 3-13. SCHEMATIC DIAGRAM – MAIN BOARD (3/3) – C808 IC402 R474 R473 C471 R499 R532 R533 C499 C810 C807 R470 C801 C802 R803 D801 D804 R802 C822 R806 C472 R480 C811 R468 C809 C805 C806 D896 R469 CN505 CN507 CNP911 CNP913 CNP912 CN915 CNP801 CNP802 RY560 IC801 IC802 R910 C831 C830 C832 R804 J309 C400 Q801 D808 D807 D806 D805 Q560 D560 CN506 C803 C804 D802 47 25V NJM4565 10k 10k 4.7 50V 47k 10k 47k 220p 0.1 47 25V 47k 47 35V 47 35V 4.7 HZS20-1LTA HZ6.8BP-TK 220 47 35V 22k 4.7 50V 47k 0.1 100k 0.1 0.22 100V 0.22 100V AK04V1 1k 3P 4P 6P 5P 4P 6P 3P 5P TA7807S TA79007S 0.15 0.1 0.1 3300 16V 10k 0.1 2SB734-T-34 10EDB40-TA2B5 10EDB40-TA2B5 10EDB40 -TA2B5 10EDB40 -TA2B5 2SC1740S-QRT 1SS133T-72 4P 6800 71V 6800 71V RBV-602LFA w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 29 29 STR-K880/K900 STR-K880/K900 DIGITAL BOARD CNS505 (Page 19) C IC101 IC100 IC102 14 8 7 3 1 1 MUTING MULTI CH IN INPUT MODE DISPLAY MUSIC MOVIE A.F.D 2CH TUNING + - INPUT SELECTOR MASTER VOLUME FL101 (FLOURESCENT DISPLAY) 42 38 35 30 23 15 10 5 1 TUNING MODE MEMORY ENTER SPEAKERS (OFF/A/B/A+B) ?/1 1 2 A B C D E F G H 3 4 5 6 7 8 9 10 11 12 13 14 15 1 4 3-14. PRINTED WIRING BOARDS – DISPLAY BOARD, POWER BOARD – :Uses unleaded solder. • See page 15 for Circuit Boards Location. w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 30 30 STR-K880/K900 STR-K880/K900 3-15. SCHEMATIC DIAGRAM – DISPLAY BOARD, POWER BOARD – • See page 43, 44 for IC Block Diagrams. R119 C135 C136 R121 R118 R116 C115 C149 C148 C147 C146 IC101 R199 R198 CNS100 S101 S102 S103 S104 S124 S105 S106 S107 S108 S109 S110 S111 R101 R108 R102 R109 R103 R110 R104 R111 R105 R106 R107 S115 S100 C100 C108 C114 C132 C133 C134 C137 C138 C139 C140 C141 C142 C143 C145 C152 C105 R120 R114 C144 C109 R117 R115 C112 C111 C110 CN101 CNP101 IC100 L103 L101 L102 FL101 RV101 RV102 C151 C150 C101 IC102 100 220p 220p 10 82k 100 10 50V 220p 220p 220p 10 50V MC74ACT08N 1 1 23P 220 220 330 330 470 470 680 680 1k 1.5k 2.2k 0.1 0.1 50V 0.22 220p 220p 220p 220p 220p 220p 220p 220p 220p 220p 0.1 50V 0.1 10 10 1k 0.1 0.1 50V 100 100 220p 220p 220p 4P 3P PT6315 JW JW JW ENCODER, ROTARY ENCODER, ROTARY 0.1 0.1 0.1 RPM7240-H4 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 31 31 STR-K880/K900 STR-K880/K900 POWER TRANSFORMER (SUB) 1 4 EXCEPT E51 E51 E51 E51 AC SELECT CNP907 VOLTAGE SELECOR 120V 220V 240V E 1 1 6 5 E 1 3 AC IN 1 2 A B C D E F G H I 3 4 5 6 7 8 9 10 11 12 1 4 1 3 1-869-146- V SPEAKER B BOARD CNP807 (Page 34) D DIGITAL BOARD CNP505 (Page 19) N MAIN BOARD CN915 (Page 25) Q MAIN BOARD CNP802 (Page 25) T901 POWER TRANSFORMER (MAIN) 3-16. PRINTED WIRING BOARDS – STANDBY BOARD, AC SELECT BOARD – :Uses unleaded solder. • See page 15 for Circuit Boards Location. • Semiconductor Location Ref. No. Location D901 A-5 D910 C-3 D911 B-3 D912 C-2 D913 B-3 D914 B-3 D915 C-3 D920 E-3 D921 E-3 D922 E-3 D923 E-3 Q901 B-2 Q921 D-3 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 32 32 STR-K880/K900 STR-K880/K900 - + - + CENTER SURROUND BACK TM501 E 1 3 R MAIN BOARD CNP806 (Page 25) M MAIN BOARD CN808 (Page 25) T MAIN BOARD WP02 (Page 25) U MAIN BOARD WP02 (Page 25) K880 K880 1 2 A B C D E 3 4 5 3-17. PRINTED WIRING BOARD – SPEAKER BOARD – :Uses unleaded solder. • See page 15 for Circuit Boards Location. w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 33 33 STR-K880/K900 STR-K880/K900 3-18. SCHEMATIC DIAGRAM – SPEAKER BOARD, STANDBY BOARD, AC SELECT BOARD – T2.5AL/250V AEP, UK, E51, SP, SP6, AUS R531 L571 L751 C915 C916 R903 R902 CNP902 R923 R922 R921 C913 C914 C924 CNP903 JW701 JW702 JW703 JW705 JW706 JW708 R751 R578 R534 R904 JW700 CNP503 CN502 RY501 CNP801 CNP804 FH951 FH901 CNP906 R901 G901 T902 R811 R810 C950 JW906 JW905 JW903 C920 RY901 C921 CNP901 RR16 CC16 RR17 CC17 Q550 TM501 D510 D920 D923 D922 D921 Q901 D911 D914 D915 D910 D912 D913 D901 F901 Q921 T901 CNP907 CNP910 S901 JW795 JW796 2.2k 2200 25V 1000 25V 2.2k 47k 2P 10k 22k 47k 0.1 0.1 1 50V 6P 4.7 4.7 82 1 4P 3P 12V 5P 3P 4P 3.3M 0.22 1/2W 0.22 1/2W 3300 16V 0.1 0.1 2P 10 0.01 10 0.01 2SC1740S-QRT 1SS133T-72 10EDB40-TA2B5 10EDB40-TA2B5 10EDB40 -TA2B5 10EDB40 -TA2B5 2SC1740S-QRT 10EDB40-TA2B5 1SS133T-72 1SS133T-72 10EDB40-TA2B5 10EDB40-TA2B5 10EDB40-TA2B5 ISS133T-72 2SC1740S-QRT 4P 3P * Ver. 1.1 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 34 34 STR-K880/K900 STR-K880/K900 MAIN BOARD CN507 (Page 25) P MAIN BOARD CN807 (Page 25) L MAIN BOARD CN801 (Page 25) O POWER TRANSFORMER T901 (Page 31) V CND CND EXCEPT CND AEP,UK,SP, SP6,AUS AEP,UK,SP,SP6,AUS CND EXCEPT CND US,CND,E51 - + - + SPEAKER IMPEDANCE USE 6-16 Ω L R FRONT B 1 1 1 5 3 4 E E 1 2 A B C D 3 4 5 6 7 3-19. PRINTED WIRING BOARD – SPEAKER B BOARD – :Uses unleaded solder. • See page 15 for Circuit Boards Location. Ver. 1.1 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 35 35 STR-K880/K900 STR-K880/K900 3-20. PRINTED WIRING BOARDS – ADCC BOARD, VIDEO 3 BOARD – :Uses unleaded solder. • See page 15 for Circuit Boards Location. MAIN BOARD CN506 (Page 25) I MAIN BOARD CNP503 (Page 25) J VIDEO BOARD CNP202 (Page 37) W IC2000 1 5 AUTO CAL MIC 1 4 5 8 L R AUDIO VIDEO VIDEO 3 IN/ PORTABLE AV IN 1 2 A B C 3 4 5 6 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 36 36 STR-K880/K900 STR-K880/K900 3-21. SCHEMATIC DIAGRAM – SPEAKER B BOARD, ADCC BOARD, VIDEO 3 BOARD – EXCEPT CND JW AEP, UK, SP, SP6, AUS AEP, UK, SP, SP6, AUS R298 R299 C293 C294 W290 C2010 C2011 C2012 TP2000 C2003 R800 R812 R2015 R2019 C2018 C2002 C2006 C2014 C2013 R2008 R2010 C2008 R2007 R2006 R2003 R2001 R2016 C2005 R2005 R2000 R2018 R2017 C2001 CNP601 JW786 JW901 JW900 0.01 CC21 CC20 RY802 RY803 RY801 RY600 CN201 J298 CNP2000 IC2000 D800 Q800 RR20 CNP600 RR21 CNP808 CNP807 R831 R830 D818 Q809 R824 TM602 J2000 D2014 D2013 1k 1k 0.1 0.1 0.033 0.022 0.022 CHASSIS GND 0.033 82 2.2k 33k 2.2k 0.1 1 50V 1 50V 0.47 50V 1 50V 560k 10k 56p 10k 1k 10k 10k 15k 33p 1M 1k 1.2k 2.2k 100p 4P 0.01 5P 4P NJM4565D 1SS133T-72 2SC1740S-QRT 10 5P 10 3P 5P 47 47 1SS133T-72 2SC1740S-QRT 2.2K ISS133T-72 ISS133T-72 Ver. 1.1 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 37 37 STR-K880/K900 STR-K880/K900 3-22. PRINTED WIRING BOARDS – VIDEO BOARD, HEADPHONE BOARD – :Uses unleaded solder. • See page 15 for Circuit Boards Location. IC203 IC304 IC804 IC807 F DIGITAL BOARD CNS509 (Page 19) K MAIN BOARD CN505 (Page 25) W VIDEO 3 BOARD CN201 (Page 35) S MAIN BOARD CN792 (Page 25) X HDMI BOARD CN5004 (Page 39) 1 1 1 1 1 3 3 3 3 6 16 9 1 8 VIDEO IN VIDEO IN VIDEO OUT VIDEO OUT VIDEO 1 VIDEO 2 MONITOR MONITOR OUT ASSIGNABLE COMPONENT VIDEO DVD DVD IN Y PB / CB / B-Y PR / CR / R-Y VIDEO IN VIDEO 2 IN PHONES 1 2 A B C D E F 3 4 5 6 7 8 9 10 1 4 • Semiconductor Location Ref. No. Location D203 C-3 D204 D-3 IC203 C-4 IC304 D-5 IC804 E-4 IC807 E-5 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 38 38 STR-K880/K900 STR-K880/K900 3-23. SCHEMATIC DIAGRAM – VIDEO BOARD, HEADPHONE BOARD – • See page 45 for IC Block Diagrams. TP701 JW200 CNP791 C223 C224 C209 C210 C214 R219 IC203 R218 R221 C200 C201 R220 R303 R302 R301 R313 JW301 C308 C309 C310 C311 C312 C313 C338 R201 R200 CNP202 C206 C207 C208 C215 CNS203 CNP204 CNP203 R304 R305 R306 R307 R308 R309 R312 R311 R310 C330 C331 C317 JW300 C790 C791 J201 J200 C213 D204 D203 C316 C315 J791 IC304 J301 C220 C221 IC804 IC807 4P 0.1 0.1 10 50V 10 50V 0.1 75 NJM2595D 75 75 47p 47p 75 75 75 75 22k 10 50V 10 50V 10 50V 10 50V 10 50V 10 50V 47 25V 75 75 3P 10 50V 10 50V 10 50V 0.1 17P 6P 3P 75 75 75 75 75 75 1k 1k 1k 0.1 0.1 47 25V 0.1 0.1 220 16V 1SS133T-72 1SS133T-72 2200P 2200P NJM2586AL 9PIN 47 25V 220 16V TA79005S TA78O5S w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 39 39 STR-K880/K900 STR-K880/K900 3-24. PRINTED WIRING BOARD – HDMI BOARD – :Uses unleaded solder. • See page 15 for Circuit Boards Location. VIDEO BOARD CNP204 (Page 37) IC5003 IC5001 IC5004 IC5002 IC5005 IC5006 DVD IN VIDEO 2 IN MONITOR OUT ASSIGNABLE HDMI X 3 1 1 5 19 1 19 1 19 1 1 2 A B C D 3 4 5 6 7 8 • Semiconductor Location Ref. No. Location IC5001 B-3 IC5002 B-1 IC5003 B-2 IC5004 C-2 IC5005 C-2 IC5006 A-4 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 40 40 STR-K880/K900 STR-K880/K900 3-25. SCHEMATIC DIAGRAM – HDMI BOARD – CN5001 CN5002 TP5001 TP5002 IC5003 TP5016 SL5001 CN5003 R5024 R5025 R5048 R5027 R5028 R5029 R5022 R5055 C5012 R5030 R5005 R5006 R5007 R5008 R5009 R5010 R5011 R5072 R5068 R5019 R5016 R5061 R5074 R5056 R5026 C5016 IC5002 C5027 C5017 C5018 C5019 IC5005 C5020 IC5004 C5013 C5014 C5015 L5013 C5007 C5006 C5005 C5001 C5023 C5022 IC5001 C5002 C5003 C5004 CN5004 R5051 R5050 R5053 C5024 R5052 C5021 IC5006 R5003 R5054 R5014 R5017 R5047 C5011 C5010 C5009 R5015 C5008 R5069 R5073 R5042 R5004 R5049 R5043 R5060 R5020 R5001 R5002 R5018 19P 19P BA33BC0FP-E2 19P 0 0 0 10k 10k 47k 10k 10k 16V 10k 0 0 0 0 0 0 0 100 100k 0 0 0 2.2k 1k 100 0.01 TK11150CSCL-G 47 10V 0.22 0.22 0.1 SN74LVC1G3157 DCKR 0.1 SN74LVC2G08 DCUR 0.33 220 4V 47 10V 0.01 0.01 0.01 0.1 0.01 0.01 TMDS341PFCR 0.01 0.01 0.01 6P 1.5k 1k 2.2k 0.33 47k 100 16V BAOOBC0WEP -E2 10k 10k 0 0 0 0.01 0.01 0.01 1k 0.01 100k 0 4.7k 0 0 4.7k 0 0 3.9k 750 1k • See page 44 for IC Block Diagram. w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 41 STR-K880/K900 – DIGITAL Board – IC1301 LC89056W-E • IC Block Diagrams 38 37 36 23 24 1 2 3 4 5 44 8 9 10 46 17 22 21 20 30 35 25 26 27 28 29 32 33 34 16 45 13 14 15 47 40 41 48 CLK 39 XSEL CE DI EMPHA AUDIO DISEL SPDIF DINO DINI DIN2 6 D.GND 7 DVDD 11 AVDD 12 AGND DOSEL0 R VIN LPF CKSEL0 XSTATE 18 DGND 19 DVDD XIN XOUT XMCK DVDD 31 DGND DO CSFLAG F0/P0/C0 F1/P1/C1 F2/P2/C2 VF/P3/C3 LOCK BPSYNC ERROR DATAO DOSEL1 CKOUT BCK LRCK CKSEL1 MODE0 MODE1 42 DGND 43 DVDD XMODE TIMING MICROCOMPUTER INTERFACE SAMPLING FREQUENCY C BIT DETECT PA/PB DETECT LOCK DETECT SYSTEM RESET MODE SELECT INPUT CIRCUIT DATA DEMODULATOR PLL CLOCK IC1401 PCM1800E SINGLE-END DEFERENTIAL CONVERTER REFERENCE SINGLE-END DEFERENTIAL CONVERTER DIGITAL ∑ MODULATOR DIGITAL ∑ MODULATOR 1/64 DECIMATION FILTER & LOW-CUT FILTER CLOCK/ TIMING CONTROL RESET/ POWER CONTROL SERIAL I/O INTERFACE & MODE/FORMAT CONTROL LIN V REF 1 REFCOM V REF 2 RIN RSTB FMT0 BYPASS FMT1 MODE1 MODE0 FSYNC 1 2 3 4 5 6 8 7 9 11 10 12 AGND VCC C PR C NR C PR C NR DGND SYSCLK DOUT BCK LRCK VDD 24 23 22 21 20 19 17 16 15 14 13 18 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 42 STR-K880/K900 IC1601, IC1602 SN74HC595ANSR IC1503 TC7WH157FU 1 2 3 4 8 7 6 5 Vcc 1Y 2B 2A 1A 1B 2Y GND 1D C1 R QA 2R 2S C2 R QB QC QD QE QF QG 3R C3 3S 2R 2S C2 R 3R C3 3S 2R 2S C2 R 3R C3 3S 2R 2S C2 R 3R C3 3S 2R 2S C2 R 3R C3 3S 2R 2S C2 R 3R C3 3S 2R 2S C2 R 3R C3 3S 3R C3 3S QH GND S-OUT OE RST LAT CLK S-IN 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 VCC 16 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 43 STR-K880/K900 IC1452 PCM1609APT SYSTEM CLOCK MANAGER SYSTEM CLOCK FUNCTION CONTROL INTERFACE SERIAL INPUT INTERFACE 4X/8X OVER SAMPLING DIGITAL FILTER WITH FUNCTION CONTROLLER ENHANCED MULTI- LEVEL DELTA- SIGMA MOJULATOR ZERO DETECT DAC AND LPF OUTPUT AMP DAC DAC DAC DAC DAC DAC DAC RST SCKI SCKO BCK TEST VDD DGND DATA1 DATA2 DATA3 ZEROA LRCK 37 38 39 40 42 43 44 45 46 47 48 41 ZERO1/GPO1 ZERO2/GPO2 ZERO3/GPO3 ZERO4/GPO4 ZERO5/GPO5 ZERO6/GPO6 NC NC VOUT6 VOUT5 VOUT4 VOUT3 1 2 3 4 5 6 7 8 9 10 11 12 VOUT2 VOUT1 VCOM VOUT7 AGND5 VCC5 AGND6 VOUT8 AGND4 VCC4 AGND3 VCC3 13 14 15 16 17 18 19 20 21 22 23 24 ML MC MDI MDO ZERO8 DATA4 ZERO7 NC VCC1 AGND1 VCC2 AGND2 36 35 34 33 31 30 29 28 27 26 25 32 AND LPF OUTPUT AMP AND LPF OUTPUT AMP AND LPF OUTPUT AMP AND LPF OUTPUT AMP AND LPF OUTPUT AMP AND LPF OUTPUT AMP AND LPF OUTPUT AMP IC501, IC601, IC701 uPC2581V-S PROTECTOR DRIVE 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 PRE DRIVE PRE DRIVE BIAS CIRCUIT REG MUTE +VOUT1 –VOUT1 COMP1 NF1 IN1 GND IN2 NF2 COMP2 –VOUT2 +VOUT2 VCC1 VCC2 VEE DRIVE – MAIN Board – – DISPLAY Board – IC101 MC74ACT08N 1 2 3 4 5 6 7 8 9 10 11 12 13 14 1A 1B 1Y 2A 2B 2Y GND VCC 4B 4A 4Y 3B 3A 3Y www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 44 STR-K880/K900 IC100 PT6315 1 2 3 4 5 4-bit latch 24-bit output latch 12-bit shift register Data selector 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 Serial interface OSC Timing generator key scan Display memory 24 bits x 12 words Key data memory (2 x 16 bits) Command decoder segment driver Grid driver Multiplexed driver 39 40 41 42 43 44 LED1 LED2 LED3 LED4 OSC DOUT DIN CLK STB KEY1 KEY2 VSS VDD SEG1/KS1 SEG2/KS2 SEG3/KS3 SEG4/KS4 SEG5/KS5 SEG6/KS6 SEG7/KS7 SEG8/KS8 SEG9/KS9 SEG10/KS10 SEG20/GRID9 SEG21/GRID8 SEG22/GRID7 SEG23/GRID6 SEG24/GRID5 GRID4 GRID3 GRID2 GRID1 VDD VSS SEG11/KS11 SEG12/KS12 SEG13/KS13 SEG14/KS14 SEG15/KS15 SEG16/KS16 VEE SEG17/GRID12 SEG18/GRID11 SEG19/GRID10 – HDMI Board – IC5005 SN74LVC1G3157DCKR 1 2 3 6 5 4 B2 GND B1 S VCC A www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 45 STR-K880/K900 – VIDEO Board – IC203 NJM2595D 6dB AMP 75Ω� DRIVER CONT1 CONT2 6dB AMP 75Ω� DRIVER CONT1 6dB AMP 75Ω� DRIVER CONT1 CONT2 CONT2 1 2 3 4 5 6 7 8 9 10 11 22 21 20 19 18 17 16 15 14 13 12 BIAS BIAS BIAS BIAS BIAS BIAS BIAS BIAS BIAS CH1_IN1 SW1 CH1_IN2 SW2 CH1_IN3 V+1 CH2_IN1 GND CH2_IN2 GND CH2_IN3 CH1_OUT P.SAVE CH2_OUT V+2 CH3_OUT V-2 CH3_IN1 V-1 CH3_IN2 GND CH3_IN3 2 3 4 5 6 7 8 9 12 11 13 15 16 1 14 10 M.OUT SW5 DVD SW3 V2 SW4 NC VEE V3 SW2 NC GND V1 SW1 VI.OUT VCC 6dB Amp 6dB Amp 75Ω Driver 75Ω Driver 6dB Amp 75Ω Driver IC304 NJM2586AL www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 46 STR-K880/K900 • IC Pin Function Description DIGITAL BOARD IC1101 MB90488BPF-G-175E1 (SYSTEM CONTROL) Pin No. Pin Name I/O Description 1 DATAO I Audio data signal input from DIR 2 GP9 I GP9 signal input from DSP 3 BST O BST signal output to DSP 4 HCS O HCS signal output to DSP 5 HACN I HACN signal input from DSP 6 XRST O Reset signal output to DSP 7 PM O PM signal output to DSP 8 GP12 O GP12 signal output to DSP 9 FL_LAT O FL driver latch signal output 10 PCM1608_RST O IC reset signal output to DAC 11 VSS — Ground terminal 12 PCM1608_ML O Latch signal output to DAC 13 PCM1608_MC O Clock signal output to DAC 14 PCM1608_MDI O IC data output to DAC 15 PCM1608_MDO I IC data input from DAC 16 T.SERIAL_CLK O Tuner clock signal output terminal 17 TUNER_DATA O Tuner data signal output terminal 18 HDOUT I HDOUT signal input from DSP 19 HDIN O HDIN signal output to DSP 20 HCLK O Clock signal output to DSP 21 TUNING_A — Tuning data output (not used) 22 TUNING_B — Tuning data output (not used) 23 VCC5 — Power supply (+3.3V) 24 FL_RESET O FL driver reset signal output 25 FL_CLK O Not used 26 XM_RST — FL driver clock signal output terminal (not used) 27 FLASH2 O FLASH2 signal output (not used) 28 FLASH1 O FLASH1 signal output (not used) 29 SDA I EEPROM data signal input terminal 30 SCL O EEPROM clock signal output terminal 31 ENC_A I Input Encoder (A) signal input 32 ENC_B I Input Encoder (B) signal input 33 UPCON — Not used 34 UPCON_CLK — Not used 35 AVCC — Analog power supply (+3.3V) 36 AVRH I Analog reference voltage input (+3.3V) 37 AVSS — Analog ground terminal 38 ADCC I ADCC signal input 39 A/D1 I Function key push signal input 40 A/D2 I Function key push signal input 41 VERSION I Version setting input terminal (DESTINATION) 42 VSS — Ground terminal 43 RDS_SIG I RDS signal detect input (connected to ground terminal) (not used) 44 MODEL I MODEL select input 45 TONE_EN_B I Tone control input from rotary encoder. 46 TONE_EN_A I Tone control input from rotary encoder. 47 XMDACMS O Not used www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 47 STR-K880/K900 Pin No. Pin Name I/O Description 48 STOP I AC off detect signal input 49 MD0 I Operation mode setting input 50 MD1 I Operation mode setting input 51 MD2 I Operation mode setting input 52 RDS_CLOCK I RDS clock signal input (Short to ground terminal) 53 RDS_DATA I RDS data signal input (Short to ground terminal) 54 SIRCS I Data signal input from the remote control sensor 55 HP_DETECT I Headphone signal input 56 POWER_KEY I Power switch key detect signal input 57 ADCC_DSP_INT I ADCC DSP interrept input 58 POWER_RY O Power relay control signal output 59 VOL_CL O Volume IC clock signal output 60 VOL_DA O Volume IC data and latch signal output 61 PROTECTOR I Protector status detect signal input 62 HP_RY O Headphone relay control signal output 63 FUSE_DETECT I Fuse detect signal input 64 VOL_ENC (B) I Volume signal input from rotary encoder 65 VOL_ENC (A) I Volume signal input from rotary encoder 66 FRONT_RY O Front A speaker relay control signal output 67 SP_B_RY O Front B speaker control signal output 68 C/SB_RY O Center speaker relay control signal output 69 REAR_RY O Rear speaker control signal output 70 SW_RY O Sub woofer control signal output 71 ANALOG_SW_CLK O Analog switch IC clock signal output 72 BRIGEABLE_RY O Brigeable relay control output 73 DO I Frequency data signal input from the tuner 74 SLATCH O Latch signal output to the tuner 75 TUNED I Tuning a frequency signal input from the tuner 76 STEREO I Stereo tuning signal input from the tuner 77 RSTX I System reset input 78 MUTE O Muting signal output to the tuner 79 X1A — Not used 80 X0A — Ground terminal 81 VSS — Ground terminal 82 X0 — Connection for a crystal resonator 83 X1 — Connection for a crystal resonator 84 VCC3 — Power supply (+3.3V) 85 ANALOG_SW_DATA O Analog switch IC data output 86 D595_DATA O I/O expander data output 87 D595_CLK O I/O expander clock output 88 D595_OE O I/O expander O/P enable output 89 D595_LAT O I/O expander latch signal output 90 SELECT 2 — Not used 91 SELECT 1 — Not used 92 BST_SEL O BST signal output terminal 93 XMODE O Reset signal output to DIR 94 CKSEL 1 O CKSEL control signal output to DIR 95 CLK O Clock signal output to DIR 96 CE O Chip enable signal output to DIR www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 48 STR-K880/K900 Pin No. Pin Name I/O Description 97 DI O Data signal output to DIR 98 DO I Data signal input from DIR 99 ERROR I PLL error muting signal input from DIR 100 XSTATE I XSTATE data signal input from DIR www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 49 STR-K880/K900 5 4-977-358-01 CUSHION 6 3-087-053-01 +BVTP2.6 (3CR) 7 A-1158-478-A DISPLAY BOARD, COMPLETE (K880) 7 A-1169-626-A DISPLAY BOARD, COMPLETE (K900) 8 1-921-102-91 WIRE (FLAT TYPE) (23 CORE) 9 3-363-099-02 SCREW (CASE 3 TP2) (BLACK) 9 3-363-099-11 SCREW (CASE 3 TP2) (SILVER) 10 2-661-145-11 CASE (BLACK) 10 2-661-145-31 CASE (SILVER) #1 7-685-646-79 SCREW +BVTP 3X8 TYPE2 IT-3 SECTION 4 EXPLODED VIEWS NOTE: • -XX and -X mean standardized parts, so they may have some difference from the original one. • The mechanical parts with no reference number in the exploded views are not supplied. • Items marked “*” are not stocked since they are seldom required for routine service. Some delay should be anticipated when ordering these items. Ref. No. Part No. Description Remark 1 2-661-142-01 VOLUME KNOB (BLACK) 1 2-661-142-11 VOLUME KNOB (SILVER) 2 2-661-141-01 MENU KNOB (BLACK) 2 2-661-141-11 MENU KNOB (SILVER) 3 2-666-844-01 LID (BLACK) 3 2-666-844-11 LID (SILVER) 4 X-2103-431-1 FRONT PANEL ASSY (BLACK) 4 X-2103-439-1 FRONT PANEL ASSY (CND) 4 X-2103-440-1 FRONT PANEL ASSY (E51) 4 X-2103-441-1 FRONT PANEL ASSY (AEP, UK) 4 X-2103-451-1 FRONT PANEL ASSY (SP, SP6, AUS) 4-1. FRONT PANEL SECTION Ref. No. Part No. Description Remark • Abbreviation AUS : Australian model. CND : Canadian model. E51 : Chilean and Peruvian models. SP : Singapore model. SP6 : Singapore and Malaysia models. • Color Indication of Appearance Parts Example: KNOB, BALANCE (WHITE) . . . (RED) ↑ ↑ Parts Color Cabinet’s Color The components identified by mark 0 or dotted line with mark 0 are critical for safety. Replace only with part number specified. Les composants identifiés par une marque 0 sont critiques pour la sécurité. Ne les remplacer que par une pièce portant le numéro spécifié. 9 9 10 #1 6 6 7 1 2 3 5 5 4 6 6 6 #1 #1 #1 chassis section supplied with RV102 supplied with RV103 not supplied not supplied not supplied not supplied not supplied not supplied 8 a b c b a c Ver. 1.1 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 50 STR-K880/K900 Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 51 4-977-358-01 CUSHION 52 3-077-331-21 +BV3 (3-CR) 53 3-701-748-00 CLAMP 54 4-249-675-01 +BV SUMITITE S 4X6 ROUND 55 3-905-609-01 SCREW (TRANSISTOR) * 56 3-703-244-00 BUSHING (2104), CORD 057 1-696-847-11 CORD, POWER (AUS) 057 1-777-071-22 CORD, POWER (E51) 057 1-777-071-82 CORD, POWER (AEP, SP, SP6, UK) 057 1-783-532-11 CORD, POWER (US, CND) 58 A-1158-469-A MAIN BOARD, COMPLETE (E51) 58 A-1158-378-A MAIN BOARD, COMPLETE (K900) 58 A-1158-475-A MAIN BOARD, COMPLETE (AEP, SP, SP6, AUS, UK) 59 1-828-993-11 WIRE (FLAT TYPE) (17 CORE) 4-2. CHASSIS SECTION-1 60 1-828-963-11 WIRE (FLAT TYPE) (11 CORE) (EXCEPT AEP, UK) 60 1-828-980-11 WIRE (FLAT TYPE) (15 CORE) (AEP, UK) 61 A-1158-393-A DIGITAL BOARD, COMPLETE (K900) 61 A-1158-480-A DIGITAL BOARD, COMPLETE (AEP, UK) 61 A-1158-583-A DIGITAL BOARD, COMPLETE (SP, SP6) 61 A-1158-589-A DIGITAL BOARD, COMPLETE (AUS) 61 A-1158-636-A DIGITAL BOARD, COMPLETE (E51) 62 A-1158-394-A HDMI BOARD, COMPLETE 63 4-956-370-12 BAND, PLUG FIXED (AUS, UK) 0F901 1-532-464-33 FUSE (T2.5AL/250V)(K880) 0F901 1-576-109-11 FUSE (5A/125V)(K900) Q503 6-702-390-01 IC MN2488-OPY-MK Q504 6-702-391-01 IC MP1620-OPY-MK (Continued on page 51) T901 54 Q604 Q754 Q753 Q654 Q704 Q703 Q503 Q534 Q533 Q504 55 Q653 Q603 55 52 #1 #1 52 #1 not supplied not supplied not supplied not supplied not supplied not supplied not supplied not supplied not supplied not supplied not supplied not supplied not supplied 52 #1 61 60 59 not supplied 58 52 TN1 #1 #1 #1 #1 #1 #3 #1 #1 #1 #1 #1 56 57 62 63 53 51 51 52 53 F901 a a c j b b c d e d e f f g g K880 E51 j k k Ver. 1.1 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 51 STR-K880/K900 4-3. CHASSIS SECTION-2 T901 54 Q604 Q754 Q753 Q654 Q704 Q703 Q503 Q534 Q533 Q504 55 Q653 Q603 55 52 #1 #1 52 #1 not supplied not supplied not supplied not supplied not supplied not supplied not supplied not supplied not supplied not supplied not supplied not supplied not supplied 52 #1 61 60 59 not supplied 58 52 TN1 #1 #1 #1 #1 #1 #3 #1 #1 #1 #1 #1 56 57 62 63 53 51 51 52 53 F901 a a c j b b c d e d e f f g g K880 E51 j k k (Continued from page 50) Q533 6-702-390-01 IC MN2488-OPY-MK (K880) Q534 6-702-391-01 IC MP1620-OPY-MK (K880) Q603 6-702-390-01 IC MN2488-OPY-MK Q604 6-702-391-01 IC MP1620-OPY-MK Q653 6-702-390-01 IC MN2488-OPY-MK Q654 6-702-391-01 IC MP1620-OPY-MK Q703 6-702-390-01 IC MN2488-OPY-MK Q704 6-702-391-01 IC MP1620-OPY-MK Q753 6-702-390-01 IC MN2488-OPY-MK Q754 6-702-391-01 IC MP1620-OPY-MK 0T901 1-443-524-11 POWER TRANSFORMER (US, CND) 0T901 1-443-525-11 POWER TRANSFORMER (AEP, SP, SP6, AUS, UK) 0T901 1-443-526-11 POWER TRANSFORMER (E51) TN1 1-693-675-11 TUNER (CND, E51, US) TN1 1-693-676-21 TUNER (AEP, UK) TN1 1-693-678-11 TUNER (SP, SP6, AUS) #1 7-685-646-79 SCREW +BVTP 3X8 TYPE2 IT-3 #3 7-682-547-04 SCREW +B 3X6 Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark Ver. 1.1 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 52 STR-K880/K900 SECTION 5 ELECTRICAL PARTS LIST NOTE: • Due to standardization, replacements in the parts list may be different from the parts specified in the diagrams or the components used on the set. • -XX and -X mean standardized parts, so they may have some difference from the original one. • RESISTORS All resistors are in ohms. METAL: Metal-film resistor. METAL OXIDE: Metal oxide-film resistor. F: nonflammable • COILS uH: µH • CAPACITORS uF: µF • Items marked “*” are not stocked since they are seldom required for routine service. Some delay should be anticipated when ordering these items. • SEMICONDUCTORS In each case, u: µ, for example: uA. . : µA. . uPA. . : µPA. . uPB. . : µPB. . uPC. . : µPC. . uPD. . : µPD. . • Abbreviation AUS : Australian model. CND : Canadian model. E51 : Chilean and Peruvian models. Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark AC SELECT BOARD (E51) *************** < CONNECTOR > * CNP910 1-564-687-11 PIN, CONNECTOR (3.96mm PITCH) 3P < SWITCH > 0S901 1-571-437-21 SWITCH, POWER VOLTAGE CHANGE (VOLTAGE SELECTOR) ************************************************************* ADCC BOARD *********** < CAPACITOR > C2001 1-128-809-11 CERAMIC 100PF 5% 50V C2002 1-126-160-11 ELECT 1uF 20% 50V C2003 1-127-882-31 CERAMIC 0.033uF 10% 50V C2005 1-128-803-11 CERAMIC 33PF 5% 50V C2006 1-126-160-11 ELECT 1uF 20% 50V C2008 1-128-806-11 CERAMIC 56PF 5% 50V C2010 1-127-882-31 CERAMIC 0.033uF 10% 50V C2011 1-127-880-11 CERAMIC 0.022uF 10% 50V C2012 1-127-880-11 CERAMIC 0.022uF 10% 50V C2013 1-126-160-11 ELECT 1uF 20% 50V C2014 1-124-465-00 ELECT 0.47uF 20% 50V C2018 1-127-888-11 CERAMIC 0.1uF 10% 50V < CONNECTOR > CNP2000 1-784-921-11 PIN, CONNECTOR 4P < DIODE > D2013 8-719-991-33 DIODE 1SS133T-72 D2014 8-719-991-33 DIODE 1SS133T-72 < IC > IC2000 8-759-167-88 IC NJM4565D < JACK > J2000 1-820-056-11 SMALL TYPE JACK (AUTO CAL MIC) < RESISTOR > R2000 1-247-831-91 CARBON 1K 5% 1/4W R2001 1-249-429-11 CARBON 10K 5% 1/4W R2003 1-249-429-11 CARBON 10K 5% 1/4W R2005 1-247-903-00 CARBON 1M 5% 1/4W R2006 1-247-831-91 CARBON 1K 5% 1/4W R2007 1-249-429-11 CARBON 10K 5% 1/4W R2008 1-247-897-11 CARBON 560K 5% 1/4W R2010 1-249-429-11 CARBON 10K 5% 1/4W R2015 1-249-435-11 CARBON 33K 5% 1/4W R2016 1-249-431-11 CARBON 15K 5% 1/4W R2017 1-249-421-11 CARBON 2.2K 5% 1/4W R2018 1-249-418-11 CARBON 1.2K 5% 1/4W R2019 1-249-421-11 CARBON 2.2K 5% 1/4W ************************************************************* A-1158-393-A DIGITAL BOARD, COMPLETE (K900) A-1158-480-A DIGITAL BOARD, COMPLETE (AEP, UK) A-1158-583-A DIGITAL BOARD, COMPLETE (SP, SP6) A-1158-589-A DIGITAL BOARD, COMPLETE (AUS) A-1158-636-A DIGITAL BOARD, COMPLETE (E51) *********************** 7-685-646-79 SCREW +BVTP 3X8 TYPE2 IT-3 < CAPACITOR > C1001 1-126-925-91 ELECT 470uF 20% 10V C1002 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1004 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1005 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1021 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1022 1-126-925-91 ELECT 470uF 20% 10V C1031 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1032 1-126-925-91 ELECT 470uF 20% 10V C1063 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V (AEP, UK) C1064 1-126-947-11 ELECT 47uF 20% 16V (AEP, UK) C1100 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1102 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1103 1-126-947-11 ELECT 47uF 20% 16V C1104 1-216-864-11 SHORT CHIP 0 C1105 1-216-864-11 SHORT CHIP 0 C1107 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1108 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1118 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1119 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1120 1-162-974-11 CERAMIC CHIP 0.01uF 50V When indicating parts by reference number, please include the board name. The components identified by mark 0 or dotted line with mark 0 are critical for safety. Replace only with part number specified. Les composants identifiés par une marque 0 sont critiques pour la sécurité. Ne les remplacer que par une pièce portant le numéro spécifié. DIGITAL ADCC AC SELECT SP : Singapore model. SP6 : Singapore and Malaysia models. Ver. 1.1 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 53 STR-K880/K900 Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark C1121 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1122 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1123 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1124 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1129 1-162-974-11 CERAMIC CHIP 0.01uF 50V C1130 1-162-974-11 CERAMIC CHIP 0.01uF 50V C1131 1-162-974-11 CERAMIC CHIP 0.01uF 50V C1132 1-162-974-11 CERAMIC CHIP 0.01uF 50V C1137 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C1138 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1139 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1140 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1142 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1144 1-162-974-11 CERAMIC CHIP 0.01uF 50V C1145 1-162-974-11 CERAMIC CHIP 0.01uF 50V C1146 1-162-974-11 CERAMIC CHIP 0.01uF 50V C1149 1-162-960-11 CERAMIC CHIP 220PF 10% 50V C1171 1-162-974-11 CERAMIC CHIP 0.01uF 50V C1172 1-162-974-11 CERAMIC CHIP 0.01uF 50V C1251 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1252 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1253 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1254 1-162-960-11 CERAMIC CHIP 220PF 10% 50V C1255 1-162-960-11 CERAMIC CHIP 220PF 10% 50V C1299 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1301 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1302 1-162-974-11 CERAMIC CHIP 0.01uF 50V C1303 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1304 1-162-974-11 CERAMIC CHIP 0.01uF 50V C1305 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1306 1-126-947-11 ELECT 47uF 20% 16V C1308 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1309 1-162-918-11 CERAMIC CHIP 18PF 5% 50V C1310 1-162-918-11 CERAMIC CHIP 18PF 5% 50V C1312 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1313 1-162-927-11 CERAMIC CHIP 100PF 5% 50V C1314 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1315 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1351 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1354 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1355 1-104-662-91 ELECT 22uF 20% 25V C1357 1-162-905-11 CERAMIC CHIP 1PF 0.25PF 50V C1358 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1359 1-126-916-11 ELECT 1000uF 20% 6.3V C1360 1-162-923-11 CERAMIC CHIP 47PF 5% 50V C1361 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1362 1-162-974-11 CERAMIC CHIP 0.01uF 50V C1401 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1402 1-126-947-11 ELECT 47uF 20% 16V C1403 1-126-964-11 ELECT 10uF 20% 50V C1404 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1405 1-162-962-11 CERAMIC CHIP 470PF 10% 50V C1406 1-126-963-11 ELECT 4.7uF 20% 50V C1407 1-126-963-11 ELECT 4.7uF 20% 50V C1408 1-162-962-11 CERAMIC CHIP 470PF 10% 50V C1409 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1411 1-162-963-11 CERAMIC CHIP 680PF 10% 50V C1413 1-162-961-11 CERAMIC CHIP 330PF 10% 50V C1418 1-126-964-11 ELECT 10uF 20% 50V C1422 1-162-963-11 CERAMIC CHIP 680PF 10% 50V C1423 1-162-961-11 CERAMIC CHIP 330PF 10% 50V C1428 1-126-964-11 ELECT 10uF 20% 50V C1432 1-162-963-11 CERAMIC CHIP 680PF 10% 50V C1433 1-162-961-11 CERAMIC CHIP 330PF 10% 50V C1438 1-126-964-11 ELECT 10uF 20% 50V C1441 1-162-963-11 CERAMIC CHIP 680PF 10% 50V C1442 1-162-961-11 CERAMIC CHIP 330PF 10% 50V C1448 1-126-964-11 ELECT 10uF 20% 50V C1450 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1451 1-162-963-11 CERAMIC CHIP 680PF 10% 50V C1453 1-162-961-11 CERAMIC CHIP 330PF 10% 50V C1454 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1457 1-126-964-11 ELECT 10uF 20% 50V C1458 1-126-964-11 ELECT 10uF 20% 50V C1460 1-126-964-11 ELECT 10uF 20% 50V C1462 1-162-963-11 CERAMIC CHIP 680PF 10% 50V C1463 1-162-961-11 CERAMIC CHIP 330PF 10% 50V C1468 1-126-964-11 ELECT 10uF 20% 50V C1472 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1473 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1478 1-126-964-11 ELECT 10uF 20% 50V C1481 1-162-961-11 CERAMIC CHIP 330PF 10% 50V C1483 1-162-963-11 CERAMIC CHIP 680PF 10% 50V C1487 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V C1491 1-126-964-11 ELECT 10uF 20% 50V C1494 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1495 1-162-960-11 CERAMIC CHIP 220PF 10% 50V C1501 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1502 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1503 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1504 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1505 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1506 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1507 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1508 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1509 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1510 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1511 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1513 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1514 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1515 1-126-925-91 ELECT 470uF 20% 10V C1516 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1517 1-126-925-91 ELECT 470uF 20% 10V C1518 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1519 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1520 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1521 1-162-920-11 CERAMIC CHIP 27PF 5% 50V C1522 1-162-920-11 CERAMIC CHIP 27PF 5% 50V C1525 1-126-925-91 ELECT 470uF 20% 10V C1540 1-216-833-11 METAL CHIP 10K 5% 1/10W C1541 1-216-833-11 METAL CHIP 10K 5% 1/10W C1542 1-216-833-11 METAL CHIP 10K 5% 1/10W C1543 1-216-833-11 METAL CHIP 10K 5% 1/10W C1544 1-216-833-11 METAL CHIP 10K 5% 1/10W C1545 1-216-833-11 METAL CHIP 10K 5% 1/10W DIGITAL www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 54 STR-K880/K900 Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark C1547 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V C1557 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V C1566 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V C1567 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V C1568 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V C1569 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V C1601 1-162-974-11 CERAMIC CHIP 0.01uF 50V C1602 1-162-927-11 CERAMIC CHIP 100PF 5% 50V C1604 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1605 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1620 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1905 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1906 1-126-925-91 ELECT 470uF 20% 10V C1908 1-126-925-91 ELECT 470uF 20% 10V C1913 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C1914 1-126-947-11 ELECT 47uF 20% 16V C2216 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C2217 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V C2218 1-126-947-11 ELECT 47uF 20% 16V < CONNECTOR > CNP503 1-784-922-11 PIN, CONNECTOR 5P CNP504 1-784-923-11 PIN, CONNECTOR 7P CNP505 1-784-925-11 PIN, CONNECTOR 10P CNS501 1-573-829-11 CONNECTOR, BOARD TO BOARD 15P CNS502 1-766-719-41 CONNECTOR, BOARD TO BOARD 10P CNS504 1-568-828-11 CONNECTOR, FFC 9P CNS505 1-784-784-11 CONNECTOR, FFC 23P CNS508 1-568-830-11 CONNECTOR, FFC 11P (EXCEPT AEP, UK) CNS508 1-784-776-11 CONNECTOR, FFC 15P (AEP, UK) CNS509 1-784-778-11 CONNECTOR, FFC 17P < DIODE > D1001 8-719-053-18 DIODE 1SR154-400TE-25 D1003 8-719-049-09 DIODE 1SS367-T3SONY D1004 8-719-049-09 DIODE 1SS367-T3SONY D1107 8-719-988-61 DIODE 1SS355TE-17 D1108 8-719-988-61 DIODE 1SS355TE-17 D1110 8-719-988-61 DIODE 1SS355TE-17 D1111 8-719-988-61 DIODE 1SS355TE-17 D1301 8-719-988-61 DIODE 1SS355TE-17 D1302 8-719-988-61 DIODE 1SS355TE-17 D1501 8-719-049-09 DIODE 1SS367-T3SONY D1502 8-719-049-09 DIODE 1SS367-T3SONY D1503 8-719-049-09 DIODE 1SS367-T3SONY D1504 8-719-049-09 DIODE 1SS367-T3SONY < FERRITE BEAD > FB1101 1-469-710-21 FERRITE, EMI (SMD) (2012) FB1302 1-469-710-21 FERRITE, EMI (SMD) (2012) FB1305 1-469-710-21 FERRITE, EMI (SMD) (2012) FB1306 1-469-710-21 FERRITE, EMI (SMD) (2012) FB1308 1-469-710-21 FERRITE, EMI (SMD) (2012) FB1405 1-469-710-21 FERRITE, EMI (SMD) (2012) FB1452 1-469-710-21 FERRITE, EMI (SMD) (2012) FB1453 1-469-710-21 FERRITE, EMI (SMD) (2012) FB1501 1-469-710-21 FERRITE, EMI (SMD) (2012) FB1502 1-469-710-21 FERRITE, EMI (SMD) (2012) FB1503 1-469-710-21 FERRITE, EMI (SMD) (2012) FB2034 1-469-710-21 FERRITE, EMI (SMD) (2012) < IC > IC1001 8-759-231-53 IC TA7805S IC1031 6-705-464-01 IC BA50BC0T IC1071 6-702-771-01 IC TA78033LS (AEP, UK) IC1101 6-806-144-01 IC MB90488BPF-G-175E1 IC1111 6-702-913-01 IC S-80929CNMC-G8ZT2G IC1131 6-705-866-01 IC BR24L16FJ-WE2 IC1301 8-759-825-15 IC LC89056W-E IC1303 8-759-242-70 IC TC7WU04F (TE12R) IC1351 6-600-466-01 IC TORX147L (VIDEO 2 IN) IC1354 6-600-466-01 IC TORX147L (VIDEO 1 IN) IC1401 8-759-560-56 IC PCM1800E/2K IC1403 8-759-710-97 IC NJM4565M (TE2) IC1404 8-759-710-97 IC NJM4565M (TE2) IC1405 8-759-710-97 IC NJM4565M (TE2) IC1406 8-759-710-97 IC NJM4565M (TE2) IC1452 6-708-785-01 IC PCM1609APT IC1501 6-705-900-01 IC CXD9718BQ IC1502 6-709-278-01 IC IS61WV6416BLL-12TLI IC1503 8-759-546-74 IC TC7WH157FU (TE12R) IC1601 8-759-268-29 IC SN74HC595ANSR IC1602 8-759-268-29 IC SN74HC595ANSR IC1901 6-701-887-02 IC SI-3004KWF IC1902 6-703-550-01 IC TA7809LS IC1904 6-705-463-01 IC BA33BC0T < JACK > J1301 1-794-972-11 JACK, PIN 1P (DVD IN/COAXIAL) < JUMPER RESISTOR > JR1005 1-216-864-11 SHORT CHIP 0 JR1008 1-216-864-11 SHORT CHIP 0 JR1015 1-211-950-11 SHORT CHIP 0 JR1016 1-211-950-11 SHORT CHIP 0 JR1019 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V JR1020 1-216-864-11 SHORT CHIP 0 JR1104 1-216-864-11 SHORT CHIP 0 JR1202 1-216-864-11 SHORT CHIP 0 (EXCEPT AEP, UK) JR1207 1-211-950-11 SHORT CHIP 0 JR1302 1-216-864-11 SHORT CHIP 0 JR1303 1-216-864-11 SHORT CHIP 0 JR1511 1-469-710-21 FERRITE, EMI (SMD) (2012) < RESISTOR > R1010 1-216-809-11 METAL CHIP 100 5% 1/10W R1011 1-216-809-11 METAL CHIP 100 5% 1/10W R1012 1-216-809-11 METAL CHIP 100 5% 1/10W R1013 1-216-809-11 METAL CHIP 100 5% 1/10W R1014 1-216-809-11 METAL CHIP 100 5% 1/10W R1015 1-216-809-11 METAL CHIP 100 5% 1/10W R1016 1-216-809-11 METAL CHIP 100 5% 1/10W R1017 1-216-809-11 METAL CHIP 100 5% 1/10W R1035 1-216-825-11 METAL CHIP 2.2K 5% 1/10W R1039 1-216-833-11 METAL CHIP 10K 5% 1/10W DIGITAL www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 55 STR-K880/K900 Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark R1041 1-216-809-11 METAL CHIP 100 5% 1/10W R1042 1-216-809-11 METAL CHIP 100 5% 1/10W R1044 1-216-809-11 METAL CHIP 100 5% 1/10W R1049 1-216-833-11 METAL CHIP 10K 5% 1/10W R1058 1-216-813-11 METAL CHIP 220 5% 1/10W (AEP, UK) R1059 1-216-813-11 METAL CHIP 220 5% 1/10W (AEP, UK) R1061 1-216-809-11 METAL CHIP 100 5% 1/10W R1062 1-216-809-11 METAL CHIP 100 5% 1/10W R1063 1-216-809-11 METAL CHIP 100 5% 1/10W R1065 1-216-809-11 METAL CHIP 100 5% 1/10W R1066 1-216-809-11 METAL CHIP 100 5% 1/10W R1067 1-216-809-11 METAL CHIP 100 5% 1/10W R1068 1-216-809-11 METAL CHIP 100 5% 1/10W R1072 1-216-827-11 METAL CHIP 3.3K 5% 1/10W R1073 1-216-827-11 METAL CHIP 3.3K 5% 1/10W R1076 1-216-809-11 METAL CHIP 100 5% 1/10W R1077 1-216-809-11 METAL CHIP 100 5% 1/10W R1078 1-216-809-11 METAL CHIP 100 5% 1/10W R1081 1-216-809-11 METAL CHIP 100 5% 1/10W R1082 1-216-809-11 METAL CHIP 100 5% 1/10W R1083 1-216-833-11 METAL CHIP 10K 5% 1/10W R1084 1-216-809-11 METAL CHIP 100 5% 1/10W R1088 1-216-833-11 METAL CHIP 10K 5% 1/10W R1094 1-216-833-11 METAL CHIP 10K 5% 1/10W (EXCEPT AEP, UK) R1095 1-216-833-11 METAL CHIP 10K 5% 1/10W (EXCEPT AEP, UK) R1096 1-216-833-11 METAL CHIP 10K 5% 1/10W R1097 1-216-845-11 METAL CHIP 100K 5% 1/10W R1103 1-216-864-11 SHORT CHIP 0 R1105 1-216-833-11 METAL CHIP 10K 5% 1/10W R1106 1-216-809-11 METAL CHIP 100 5% 1/10W R1107 1-216-825-11 METAL CHIP 2.2K 5% 1/10W R1108 1-216-825-11 METAL CHIP 2.2K 5% 1/10W R1109 1-216-825-11 METAL CHIP 2.2K 5% 1/10W R1110 1-216-825-11 METAL CHIP 2.2K 5% 1/10W R1111 1-216-825-11 METAL CHIP 2.2K 5% 1/10W R1112 1-216-809-11 METAL CHIP 100 5% 1/10W R1113 1-216-809-11 METAL CHIP 100 5% 1/10W R1114 1-216-825-11 METAL CHIP 2.2K 5% 1/10W R1115 1-216-809-11 METAL CHIP 100 5% 1/10W R1116 1-216-809-11 METAL CHIP 100 5% 1/10W R1117 1-216-821-11 METAL CHIP 1K 5% 1/10W R1118 1-216-821-11 METAL CHIP 1K 5% 1/10W R1119 1-216-821-11 METAL CHIP 1K 5% 1/10W R1120 1-216-821-11 METAL CHIP 1K 5% 1/10W R1121 1-216-809-11 METAL CHIP 100 5% 1/10W R1122 1-216-809-11 METAL CHIP 100 5% 1/10W R1123 1-216-809-11 METAL CHIP 100 5% 1/10W R1124 1-216-809-11 METAL CHIP 100 5% 1/10W R1125 1-216-809-11 METAL CHIP 100 5% 1/10W R1126 1-216-809-11 METAL CHIP 100 5% 1/10W R1127 1-216-809-11 METAL CHIP 100 5% 1/10W R1128 1-216-809-11 METAL CHIP 100 5% 1/10W R1129 1-216-809-11 METAL CHIP 100 5% 1/10W R1130 1-216-833-11 METAL CHIP 10K 5% 1/10W R1134 1-216-809-11 METAL CHIP 100 5% 1/10W R1135 1-216-809-11 METAL CHIP 100 5% 1/10W R1136 1-216-809-11 METAL CHIP 100 5% 1/10W R1137 1-216-809-11 METAL CHIP 100 5% 1/10W R1140 1-216-809-11 METAL CHIP 100 5% 1/10W R1142 1-216-809-11 METAL CHIP 100 5% 1/10W R1143 1-216-809-11 METAL CHIP 100 5% 1/10W R1144 1-216-809-11 METAL CHIP 100 5% 1/10W R1149 1-216-809-11 METAL CHIP 100 5% 1/10W R1150 1-216-809-11 METAL CHIP 100 5% 1/10W R1151 1-216-809-11 METAL CHIP 100 5% 1/10W R1152 1-216-809-11 METAL CHIP 100 5% 1/10W R1153 1-216-809-11 METAL CHIP 100 5% 1/10W R1154 1-216-809-11 METAL CHIP 100 5% 1/10W R1155 1-216-809-11 METAL CHIP 100 5% 1/10W R1156 1-216-864-11 SHORT CHIP 0 R1157 1-216-864-11 SHORT CHIP 0 R1159 1-216-827-11 METAL CHIP 3.3K 5% 1/10W R1160 1-216-809-11 METAL CHIP 100 5% 1/10W R1161 1-216-809-11 METAL CHIP 100 5% 1/10W R1162 1-216-809-11 METAL CHIP 100 5% 1/10W R1164 1-216-864-11 SHORT CHIP 0 R1175 1-216-809-11 METAL CHIP 100 5% 1/10W (AEP, UK) R1179 1-216-833-11 METAL CHIP 10K 5% 1/10W R1180 1-216-833-11 METAL CHIP 10K 5% 1/10W R1181 1-216-833-11 METAL CHIP 10K 5% 1/10W R1182 1-216-833-11 METAL CHIP 10K 5% 1/10W R1183 1-216-833-11 METAL CHIP 10K 5% 1/10W R1184 1-216-833-11 METAL CHIP 10K 5% 1/10W R1185 1-216-833-11 METAL CHIP 10K 5% 1/10W R1186 1-216-833-11 METAL CHIP 10K 5% 1/10W R1187 1-216-833-11 METAL CHIP 10K 5% 1/10W R1188 1-216-833-11 METAL CHIP 10K 5% 1/10W R1189 1-216-833-11 METAL CHIP 10K 5% 1/10W R1190 1-216-833-11 METAL CHIP 10K 5% 1/10W R1192 1-216-833-11 METAL CHIP 10K 5% 1/10W R1193 1-216-833-11 METAL CHIP 10K 5% 1/10W (E51) R1193 1-216-837-11 METAL CHIP 22K 5% 1/10W (AUS) R1193 1-216-841-11 METAL CHIP 47K 5% 1/10W (AEP, SP, SP6, UK) R1194 1-216-825-11 METAL CHIP 2.2K 5% 1/10W (AEP, UK) R1194 1-216-829-11 METAL CHIP 4.7K 5% 1/10W (SP, SP6) R1194 1-216-841-11 METAL CHIP 47K 5% 1/10W (E51, AUS) R1194 1-216-864-11 SHORT CHIP 0 (K900) R1201 1-216-837-11 METAL CHIP 22K 5% 1/10W R1251 1-216-840-11 METAL CHIP 39K 5% 1/10W R1252 1-216-840-11 METAL CHIP 39K 5% 1/10W R1260 1-216-821-11 METAL CHIP 1K 5% 1/10W R1261 1-216-821-11 METAL CHIP 1K 5% 1/10W R1301 1-216-830-11 METAL CHIP 5.6K 5% 1/10W R1302 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R1303 1-216-839-11 METAL CHIP 33K 5% 1/10W R1304 1-216-809-11 METAL CHIP 100 5% 1/10W R1305 1-216-819-11 METAL CHIP 680 5% 1/10W DIGITAL Ver. 1.1 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 56 STR-K880/K900 Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark DISPLAY R1306 1-216-801-11 METAL CHIP 22 5% 1/10W R1307 1-216-809-11 METAL CHIP 100 5% 1/10W R1308 1-216-809-11 METAL CHIP 100 5% 1/10W R1309 1-216-809-11 METAL CHIP 100 5% 1/10W R1310 1-216-857-11 METAL CHIP 1M 5% 1/10W R1311 1-216-809-11 METAL CHIP 100 5% 1/10W R1312 1-216-809-11 METAL CHIP 100 5% 1/10W R1313 1-216-809-11 METAL CHIP 100 5% 1/10W R1314 1-216-833-11 METAL CHIP 10K 5% 1/10W R1315 1-216-809-11 METAL CHIP 100 5% 1/10W R1316 1-216-809-11 METAL CHIP 100 5% 1/10W R1318 1-216-833-11 METAL CHIP 10K 5% 1/10W R1319 1-216-864-11 SHORT CHIP 0 R1321 1-216-864-11 SHORT CHIP 0 R1323 1-216-833-11 METAL CHIP 10K 5% 1/10W R1351 1-216-809-11 METAL CHIP 100 5% 1/10W R1354 1-216-809-11 METAL CHIP 100 5% 1/10W R1355 1-218-285-11 METAL CHIP 75 5% 1/10W R1356 1-216-821-11 METAL CHIP 1K 5% 1/10W R1357 1-216-837-11 METAL CHIP 22K 5% 1/10W R1358 1-216-854-11 METAL CHIP 560K 5% 1/10W R1359 1-216-809-11 METAL CHIP 100 5% 1/10W R1360 1-216-809-11 METAL CHIP 100 5% 1/10W R1362 1-216-809-11 METAL CHIP 100 5% 1/10W R1401 1-216-821-11 METAL CHIP 1K 5% 1/10W R1402 1-216-825-11 METAL CHIP 2.2K 5% 1/10W R1403 1-216-833-11 METAL CHIP 10K 5% 1/10W R1407 1-216-809-11 METAL CHIP 100 5% 1/10W R1414 1-218-867-11 METAL CHIP 6.8K 5% 1/10W R1416 1-216-821-11 METAL CHIP 1K 5% 1/10W R1420 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V R1421 1-218-867-11 METAL CHIP 6.8K 5% 1/10W R1424 1-218-867-11 METAL CHIP 6.8K 5% 1/10W R1425 1-216-864-11 SHORT CHIP 0 R1426 1-216-821-11 METAL CHIP 1K 5% 1/10W R1434 1-218-867-11 METAL CHIP 6.8K 5% 1/10W R1435 1-216-864-11 SHORT CHIP 0 R1436 1-216-821-11 METAL CHIP 1K 5% 1/10W R1444 1-218-867-11 METAL CHIP 6.8K 5% 1/10W R1445 1-216-864-11 SHORT CHIP 0 R1446 1-216-821-11 METAL CHIP 1K 5% 1/10W R1454 1-218-867-11 METAL CHIP 6.8K 5% 1/10W R1455 1-216-864-11 SHORT CHIP 0 R1460 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V R1461 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V R1463 1-218-867-11 METAL CHIP 6.8K 5% 1/10W R1464 1-216-864-11 SHORT CHIP 0 R1466 1-216-821-11 METAL CHIP 1K 5% 1/10W R1470 1-216-832-11 METAL CHIP 8.2K 5% 1/10W R1471 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V R1472 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V R1473 1-216-832-11 METAL CHIP 8.2K 5% 1/10W R1474 1-216-833-11 METAL CHIP 10K 5% 1/10W R1475 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V R1476 1-216-821-11 METAL CHIP 1K 5% 1/10W R1483 1-218-867-11 METAL CHIP 6.8K 5% 1/10W R1484 1-216-864-11 SHORT CHIP 0 R1486 1-216-821-11 METAL CHIP 1K 5% 1/10W R1490 1-218-867-11 METAL CHIP 6.8K 5% 1/10W R1491 1-218-867-11 METAL CHIP 6.8K 5% 1/10W R1492 1-218-867-11 METAL CHIP 6.8K 5% 1/10W R1493 1-218-867-11 METAL CHIP 6.8K 5% 1/10W R1494 1-218-867-11 METAL CHIP 6.8K 5% 1/10W R1495 1-218-867-11 METAL CHIP 6.8K 5% 1/10W R1501 1-216-809-11 METAL CHIP 100 5% 1/10W R1502 1-216-809-11 METAL CHIP 100 5% 1/10W R1503 1-216-813-11 METAL CHIP 220 5% 1/10W R1504 1-216-809-11 METAL CHIP 100 5% 1/10W R1505 1-216-809-11 METAL CHIP 100 5% 1/10W R1506 1-216-809-11 METAL CHIP 100 5% 1/10W R1507 1-216-809-11 METAL CHIP 100 5% 1/10W R1508 1-216-809-11 METAL CHIP 100 5% 1/10W R1509 1-216-809-11 METAL CHIP 100 5% 1/10W R1510 1-216-809-11 METAL CHIP 100 5% 1/10W R1511 1-216-809-11 METAL CHIP 100 5% 1/10W R1512 1-216-821-11 METAL CHIP 1K 5% 1/10W R1513 1-216-833-11 METAL CHIP 10K 5% 1/10W R1514 1-216-833-11 METAL CHIP 10K 5% 1/10W R1515 1-216-857-11 METAL CHIP 1M 5% 1/10W R1523 1-216-813-11 METAL CHIP 220 5% 1/10W R1524 1-216-864-11 SHORT CHIP 0 R1530 1-216-845-11 METAL CHIP 100K 5% 1/10W R1541 1-216-813-11 METAL CHIP 220 5% 1/10W R1555 1-216-813-11 METAL CHIP 220 5% 1/10W R1556 1-216-809-11 METAL CHIP 100 5% 1/10W R1557 1-216-813-11 METAL CHIP 220 5% 1/10W R1570 1-216-833-11 METAL CHIP 10K 5% 1/10W R1571 1-216-833-11 METAL CHIP 10K 5% 1/10W R1572 1-216-833-11 METAL CHIP 10K 5% 1/10W R1573 1-216-833-11 METAL CHIP 10K 5% 1/10W R1574 1-216-833-11 METAL CHIP 10K 5% 1/10W R1635 1-216-825-11 METAL CHIP 2.2K 5% 1/10W R1636 1-216-825-11 METAL CHIP 2.2K 5% 1/10W < COMPOSITION CIRCUIT BLOCK > RB1500 1-233-576-11 RES, CHIP NETWORK 100 (3216) RB1501 1-233-576-11 RES, CHIP NETWORK 100 (3216) RB1502 1-233-576-11 RES, CHIP NETWORK 100 (3216) RB1503 1-233-576-11 RES, CHIP NETWORK 100 (3216) RB1504 1-233-576-11 RES, CHIP NETWORK 100 (3216) RB1506 1-233-576-11 RES, CHIP NETWORK 100 (3216) RB1507 1-233-576-11 RES, CHIP NETWORK 100 (3216) RB1508 1-233-576-11 RES, CHIP NETWORK 100 (3216) < VIBRATOR > X1101 1-813-448-21 PIEZOELECTRIC OSCILLATOR (24MHz) X1301 1-795-126-21 VIBRATOR, CRYSTAL (12.288MHz) X1502 1-813-276-21 QUARTZ CRYSTAL (13.9MHz) ************************************************************* A-1158-478-A DISPLAY BOARD, COMPLETE (K880) A-1169-626-A DISPLAY BOARD, COMPLETE (K900) ************************ < CAPACITOR > C100 1-127-888-11 CERAMIC 0.1uF 10% 50V C101 1-127-888-11 CERAMIC 0.1uF 10% 50V DIGITAL www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 57 STR-K880/K900 Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark C105 1-126-795-11 ELECT 10uF 20% 50V C106 1-127-868-11 CERAMIC 2200PF 10% 50V C107 1-127-868-11 CERAMIC 2200PF 10% 50V C108 1-127-888-11 CERAMIC 0.1uF 10% 50V C109 1-127-888-11 CERAMIC 0.1uF 10% 50V C110 1-162-286-31 CERAMIC 220PF 10% 50V C111 1-162-286-31 CERAMIC 220PF 10% 50V C112 1-162-286-31 CERAMIC 220PF 10% 50V C114 1-135-798-11 CERAMIC 0.22uF 50V C115 1-126-795-11 ELECT 10uF 20% 50V C132 1-162-286-31 CERAMIC 220PF 10% 50V C133 1-162-286-31 CERAMIC 220PF 10% 50V C134 1-162-286-31 CERAMIC 220PF 10% 50V C135 1-162-286-31 CERAMIC 220PF 10% 50V C136 1-162-286-31 CERAMIC 220PF 10% 50V C137 1-162-286-31 CERAMIC 220PF 10% 50V C138 1-162-286-31 CERAMIC 220PF 10% 50V C139 1-162-286-31 CERAMIC 220PF 10% 50V C140 1-162-286-31 CERAMIC 220PF 10% 50V C141 1-162-286-31 CERAMIC 220PF 10% 50V C142 1-162-286-31 CERAMIC 220PF 10% 50V C143 1-162-286-31 CERAMIC 220PF 10% 50V C144 1-127-888-11 CERAMIC 0.1uF 10% 50V C145 1-127-888-11 CERAMIC 0.1uF 10% 50V C146 1-126-795-11 ELECT 10uF 20% 50V C147 1-162-286-31 CERAMIC 220PF 10% 50V C148 1-162-286-31 CERAMIC 220PF 10% 50V C149 1-162-286-31 CERAMIC 220PF 10% 50V C150 1-127-888-11 CERAMIC 0.1uF 10% 50V C151 1-127-888-11 CERAMIC 0.1uF 10% 50V C152 1-127-888-11 CERAMIC 0.1uF 10% 50V < CONNECTOR > CNS100 1-784-784-11 CONNECTOR, FFC 23P < FLUORESCENT INDICATOR TUBE > FL101 1-519-866-01 VACUUM FLOURESCENT DISPLAYS < IC > IC100 8-759-643-83 IC PT6315 IC101 8-759-036-90 IC MC74ACT08N IC102 6-600-174-01 IC RPM7240-H4 < RESISTOR > R101 1-249-409-11 CARBON 220 5% 1/4W R102 1-249-411-11 CARBON 330 5% 1/4W R103 1-249-413-11 CARBON 470 5% 1/4W R104 1-249-415-11 CARBON 680 5% 1/4W R105 1-247-831-91 CARBON 1K 5% 1/4W R106 1-249-419-11 CARBON 1.5K 5% 1/4W R107 1-249-421-11 CARBON 2.2K 5% 1/4W R108 1-249-409-11 CARBON 220 5% 1/4W R109 1-249-411-11 CARBON 330 5% 1/4W R110 1-249-413-11 CARBON 470 5% 1/4W R111 1-249-415-11 CARBON 680 5% 1/4W R115 1-247-807-31 CARBON 100 5% 1/4W R116 1-247-807-31 CARBON 100 5% 1/4W R117 1-247-807-31 CARBON 100 5% 1/4W R118 1-249-440-11 CARBON 82K 5% 1/4W R119 1-247-807-31 CARBON 100 5% 1/4W 0R120 1-249-393-11 CARBON 10 5% 1/4W 0R121 1-249-393-11 CARBON 10 5% 1/4W 0R198 1-249-381-11 CARBON 1 5% 1/4W 0R199 1-249-381-11 CARBON 1 5% 1/4W < VARIABLE RESISTOR > RV101 1-418-817-11 ENCODER, ROTARY (INPUT SELECTOR) RV102 1-418-725-41 ENCODER, ROTARY (12 TYPE) (MASTER VOLUME) < SWITCH > S101 1-771-410-21 SWITCH, TACTILE (MUTING) S102 1-771-410-21 SWITCH, TACTILE (MULTI CH IN) S103 1-771-410-21 SWITCH, TACTILE (INPUT MODE) S104 1-771-410-21 SWITCH, TACTILE (DISPLAY) S105 1-771-410-21 SWITCH, TACTILE (MOVIE) S106 1-771-410-21 SWITCH, TACTILE (A. F. D) S107 1-771-410-21 SWITCH, TACTILE (2CH) S108 1-771-410-21 SWITCH, TACTILE (MEMORY/ EMTER) S109 1-771-410-21 SWITCH, TACTILE (TUNING –) S110 1-771-410-21 SWITCH, TACTILE (TUNING MODE) S111 1-771-410-21 SWITCH, TACTILE (TUNING +) S124 1-771-410-21 SWITCH, TACTILE (MUSIC) ************************************************************* A-1158-394-A HDMI BOARD, COMPLETE ********************* < CAPACITOR > C5001 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C5002 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C5003 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C5004 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C5005 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C5006 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C5007 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C5008 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C5009 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C5010 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C5011 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C5012 1-117-681-11 ELECT CHIP 100uF 20% 16V C5013 1-128-934-91 CERAMIC CHIP 0.33uF 20% 10V C5014 1-126-246-11 ELECT CHIP 220uF 20% 4V C5015 1-128-994-21 ELECT CHIP 47uF 20% 10V C5016 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C5017 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V C5018 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V C5019 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C5020 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C5021 1-117-681-11 ELECT CHIP 100uF 20% 16V C5022 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C5023 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C5024 1-128-934-91 CERAMIC CHIP 0.33uF 20% 10V C5027 1-128-994-21 ELECT CHIP 47uF 20% 10V HDMI www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 58 STR-K880/K900 Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark < CONNECTOR > CN5001 1-818-086-41 HDMI CONNECTOR (DVD IN/ASSIGNABLE/HDMI) CN5002 1-818-086-41 HDMI CONNECTOR (VIDEO 2 IN/ASSIGNABLE/HDMI) CN5003 1-818-086-41 HDMI CONNECTOR (MONITOR OUT/HDMI) * CN5004 1-770-470-21 PIN, CONNECTOR (PC BOARD) 6P < IC > IC5001 6-709-221-01 IC TMDS341PFCR IC5002 6-705-337-01 IC TK11150CSCL-G IC5003 6-705-468-01 IC BA33BC0FP-E2 IC5004 6-704-351-01 IC SN74LVC2G08DCUR IC5005 6-707-207-01 IC SN74LVC1G3157DCKR IC5006 6-706-740-01 IC BA00BC0WFP-E2 < COIL > L5013 1-400-862-11 BEAD, FERRITE < RESISTOR > R5001 1-218-861-11 METAL CHIP 3.9K 0.5% 1/10W R5002 1-218-844-11 METAL CHIP 750 0.5% 1/10W R5003 1-216-833-11 METAL CHIP 10K 5% 1/10W R5004 1-216-864-11 SHORT CHIP 0 R5005 1-216-864-11 SHORT CHIP 0 R5006 1-216-864-11 SHORT CHIP 0 R5007 1-216-864-11 SHORT CHIP 0 R5008 1-216-864-11 SHORT CHIP 0 R5009 1-216-864-11 SHORT CHIP 0 R5010 1-216-864-11 SHORT CHIP 0 R5011 1-216-864-11 SHORT CHIP 0 R5014 1-216-864-11 SHORT CHIP 0 R5015 1-216-821-11 METAL CHIP 1K 5% 1/10W R5016 1-216-864-11 SHORT CHIP 0 R5017 1-216-864-11 SHORT CHIP 0 R5018 1-216-821-11 METAL CHIP 1K 5% 1/10W R5019 1-216-864-11 SHORT CHIP 0 R5020 1-216-864-11 SHORT CHIP 0 R5022 1-216-833-11 METAL CHIP 10K 5% 1/10W R5024 1-216-864-11 SHORT CHIP 0 R5025 1-216-864-11 SHORT CHIP 0 R5026 1-216-809-11 METAL CHIP 100 5% 1/10W R5027 1-216-833-11 METAL CHIP 10K 5% 1/10W R5028 1-216-833-11 METAL CHIP 10K 5% 1/10W R5029 1-216-841-11 METAL CHIP 47K 5% 1/10W R5030 1-216-833-11 METAL CHIP 10K 5% 1/10W R5042 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R5043 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R5047 1-216-864-11 SHORT CHIP 0 R5048 1-216-864-11 SHORT CHIP 0 R5049 1-216-864-11 SHORT CHIP 0 R5050 1-216-821-11 METAL CHIP 1K 5% 1/10W R5051 1-216-823-11 METAL CHIP 1.5K 5% 1/10W R5052 1-216-841-11 METAL CHIP 47K 5% 1/10W R5053 1-216-825-11 METAL CHIP 2.2K 5% 1/10W R5054 1-216-833-11 METAL CHIP 10K 5% 1/10W R5055 1-216-833-11 METAL CHIP 10K 5% 1/10W R5056 1-216-821-11 METAL CHIP 1K 5% 1/10W R5060 1-216-864-11 SHORT CHIP 0 R5061 1-216-864-11 SHORT CHIP 0 R5068 1-216-845-11 METAL CHIP 100K 5% 1/10W R5069 1-216-845-11 METAL CHIP 100K 5% 1/10W R5072 1-216-809-11 METAL CHIP 100 5% 1/10W R5073 1-216-864-11 SHORT CHIP 0 R5074 1-216-825-11 METAL CHIP 2.2K 5% 1/10W ************************************************************* HEADPHONE BOARD ***************** < CAPACITOR > C790 1-127-888-11 CERAMIC 0.1uF 10% 50V C791 1-127-888-11 CERAMIC 0.1uF 10% 50V < CONNECTOR > CNP791 1-691-766-11 PLUG (MICRO CONNECTOR) 4P < JACK > J791 1-815-314-21 JACK (PHONES) < LEAD > * TP701 1-690-880-31 LEAD (WITH CONNECTOR) ************************************************************* A-1158-378-A MAIN BOARD, COMPLETE (K900) A-1158-469-A MAIN BOARD, COMPLETE (E51) A-1158-475-A MAIN BOARD, COMPLETE (AEP, SP, SP6, AUS, UK) ********************* 7-685-646-79 SCREW +BVTP 3X8 TYPE2 IT-3 < CAPACITOR > C400 1-127-888-11 CERAMIC 0.1uF 10% 50V C403 1-127-888-11 CERAMIC 0.1uF 10% 50V C408 1-126-963-11 ELECT 4.7uF 20% 50V C409 1-126-963-11 ELECT 4.7uF 20% 50V C444 1-127-868-11 CERAMIC 2200PF 10% 50V C445 1-127-888-11 CERAMIC 0.1uF 10% 50V C453 1-162-286-31 CERAMIC 220PF 10% 50V C458 1-126-963-11 ELECT 4.7uF 20% 50V C459 1-126-963-11 ELECT 4.7uF 20% 50V C463 1-162-286-31 CERAMIC 220PF 10% 50V C464 1-127-888-11 CERAMIC 0.1uF 10% 50V C468 1-162-282-31 CERAMIC 100PF 10% 50V C469 1-162-282-31 CERAMIC 100PF 10% 50V C471 1-126-963-11 ELECT 4.7uF 20% 50V C472 1-126-963-11 ELECT 4.7uF 20% 50V C481 1-126-964-11 ELECT 10uF 20% 50V C484 1-126-964-11 ELECT 10uF 20% 50V C485 1-126-964-11 ELECT 10uF 20% 50V C488 1-127-888-11 CERAMIC 0.1uF 10% 50V C490 1-126-964-11 ELECT 10uF 20% 50V (K880) C492 1-126-964-11 ELECT 10uF 20% 50V C493 1-126-964-11 ELECT 10uF 20% 50V C495 1-126-964-11 ELECT 10uF 20% 50V C499 1-162-286-31 CERAMIC 220PF 10% 50V MAIN HDMI HEADPHONE Ver. 1.1 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 59 STR-K880/K900 Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark C501 1-126-963-11 ELECT 4.7uF 20% 50V C503 1-104-658-91 ELECT 100uF 20% 10V C504 1-107-585-11 CERAMIC 5PF 0.25PF 500V C505 1-102-233-00 CERAMIC 33PF 10% 500V C506 1-162-282-31 CERAMIC 100PF 10% 50V C507 1-162-282-31 CERAMIC 100PF 10% 50V C510 1-126-947-11 ELECT 47uF 20% 25V C511 1-136-157-00 FILM 0.022uF 5% 50V C516 1-162-815-11 CERAMIC 47PF 5% 500V C517 1-162-815-11 CERAMIC 47PF 5% 500V C519 1-162-286-31 CERAMIC 220PF 10% 50V C529 1-127-876-11 CERAMIC 0.01uF 10% 50V C531 1-136-157-00 FILM 0.022uF 5% 50V (K880) C539 1-162-286-31 CERAMIC 220PF 10% 50V (K880) C540 1-126-964-11 ELECT 10uF 20% 50V C541 1-127-876-11 CERAMIC 0.01uF 10% 50V C553 1-104-658-91 ELECT 100uF 20% 10V (K880) C554 1-107-585-11 CERAMIC 5PF 0.25PF 500V (K880) C561 1-126-963-11 ELECT 4.7uF 20% 50V (K880) C565 1-102-233-00 CERAMIC 33PF 10% 500V (K880) C566 1-162-282-31 CERAMIC 100PF 10% 50V (K880) C567 1-162-282-31 CERAMIC 100PF 10% 50V (K880) C570 1-126-947-11 ELECT 47uF 20% 25V (K880) C576 1-162-815-11 CERAMIC 47PF 5% 500V (K880) C577 1-162-815-11 CERAMIC 47PF 5% 500V (K880) C580 1-126-964-11 ELECT 10uF 20% 50V (K880) C581 1-127-876-11 CERAMIC 0.01uF 10% 50V (K880) C601 1-126-963-11 ELECT 4.7uF 20% 50V C603 1-104-658-91 ELECT 100uF 20% 10V C604 1-107-583-11 CERAMIC 3PF 0.25PF 500V C605 1-102-233-00 CERAMIC 33PF 10% 500V C606 1-162-282-31 CERAMIC 100PF 10% 50V C607 1-162-282-31 CERAMIC 100PF 10% 50V C610 1-126-947-11 ELECT 47uF 20% 25V C611 1-136-157-00 FILM 0.022uF 5% 50V C619 1-162-286-31 CERAMIC 220PF 10% 50V C620 1-162-815-11 CERAMIC 47PF 5% 500V C621 1-162-815-11 CERAMIC 47PF 5% 500V C640 1-126-964-11 ELECT 10uF 20% 50V C642 1-127-876-11 CERAMIC 0.01uF 10% 50V C651 1-126-963-11 ELECT 4.7uF 20% 50V C653 1-165-722-11 ELECT 100uF 20% 10V C654 1-107-583-11 CERAMIC 3PF 0.25PF 500V C655 1-102-233-00 CERAMIC 33PF 10% 500V C656 1-162-282-31 CERAMIC 100PF 10% 50V C657 1-162-282-31 CERAMIC 100PF 10% 50V C660 1-126-947-11 ELECT 47uF 20% 25V C661 1-136-157-00 FILM 0.022uF 5% 50V C666 1-162-815-11 CERAMIC 47PF 5% 500V C669 1-162-815-11 CERAMIC 47PF 5% 500V C670 1-162-286-31 CERAMIC 220PF 10% 50V C680 1-126-964-11 ELECT 10uF 20% 50V C681 1-127-876-11 CERAMIC 0.01uF 10% 50V C691 1-127-888-11 CERAMIC 0.1uF 10% 50V C701 1-126-963-11 ELECT 4.7uF 20% 50V C702 1-126-964-11 ELECT 10uF 20% 50V C703 1-165-722-11 ELECT 100uF 20% 10V C704 1-107-583-11 CERAMIC 3PF 0.25PF 500V C705 1-102-233-00 CERAMIC 33PF 10% 500V C706 1-162-282-31 CERAMIC 100PF 10% 50V C707 1-162-282-31 CERAMIC 100PF 10% 50V C710 1-126-947-11 ELECT 47uF 20% 25V C711 1-136-157-00 FILM 0.022uF 5% 50V C716 1-162-815-11 CERAMIC 47PF 5% 500V C717 1-162-815-11 CERAMIC 47PF 5% 500V C720 1-162-286-31 CERAMIC 220PF 10% 50V C721 1-126-923-91 ELECT 220uF 20% 10V C722 1-126-964-11 ELECT 10uF 20% 50V C729 1-127-876-11 CERAMIC 0.01uF 10% 50V C732 1-128-582-11 ELECT 10uF 20% 100V C733 1-128-582-11 ELECT 10uF 20% 100V C740 1-126-964-11 ELECT 10uF 20% 50V C741 1-128-579-11 ELECT 2.2uF 20% 100V C742 1-127-876-11 CERAMIC 0.01uF 10% 50V C743 1-128-579-11 ELECT 2.2uF 20% 100V C744 1-128-579-11 ELECT 2.2uF 20% 100V C749 1-127-876-11 CERAMIC 0.01uF 10% 50V C750 1-126-964-11 ELECT 10uF 20% 50V C751 1-126-963-11 ELECT 4.7uF 20% 50V C752 1-127-876-11 CERAMIC 0.01uF 10% 50V C753 1-165-722-11 ELECT 100uF 20% 10V C754 1-107-583-11 CERAMIC 3PF 0.25PF 500V C755 1-102-233-00 CERAMIC 33PF 10% 500V C756 1-162-282-31 CERAMIC 100PF 10% 50V C757 1-162-282-31 CERAMIC 100PF 10% 50V C760 1-126-947-11 ELECT 47uF 20% 25V C761 1-136-157-00 FILM 0.022uF 5% 50V C762 1-126-964-11 ELECT 10uF 20% 50V C766 1-162-815-11 CERAMIC 47PF 5% 500V C767 1-162-815-11 CERAMIC 47PF 5% 500V C770 1-162-286-31 CERAMIC 220PF 10% 50V C791 1-126-923-91 ELECT 220uF 20% 10V C801 1-126-947-11 ELECT 47uF 20% 35V C802 1-126-947-11 ELECT 47uF 20% 35V C803 1-165-960-11 ELECT (BLOCK) 6800uF 20% 71V C804 1-165-960-11 ELECT (BLOCK) 6800uF 20% 71V C805 1-135-851-21 MYLAR 0.22uF 100V C806 1-135-851-21 MYLAR 0.22uF 100V C807 1-126-947-11 ELECT 47uF 20% 25V C808 1-126-947-11 ELECT 47uF 20% 25V C809 1-127-888-11 CERAMIC 0.1uF 10% 50V C810 1-127-888-11 CERAMIC 0.1uF 10% 50V C811 1-127-888-11 CERAMIC 0.1uF 10% 50V C822 1-126-947-11 ELECT 47uF 20% 35V MAIN www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 60 STR-K880/K900 Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark C830 1-127-888-11 CERAMIC 0.1uF 10% 50V C831 1-127-888-11 CERAMIC 0.1uF 10% 50V C832 1-126-936-11 ELECT 3300uF 20% 16V C842 1-126-947-11 ELECT 47uF 20% 25V CC01 1-162-282-31 CERAMIC 100PF 10% 50V (AEP, SP, SP6, AUS, UK) CC02 1-162-282-31 CERAMIC 100PF 10% 50V (AEP, SP, SP6, AUS, UK) CC04 1-162-282-31 CERAMIC 100PF 10% 50V (AEP, SP, SP6, AUS, UK) CC05 1-162-282-31 CERAMIC 100PF 10% 50V (AEP, SP, SP6, AUS, UK) CC06 1-162-282-31 CERAMIC 100PF 10% 50V (AEP, SP, SP6, AUS, UK) CC07 1-162-282-31 CERAMIC 100PF 10% 50V (AEP, SP, SP6, AUS, UK) CC08 1-162-282-31 CERAMIC 100PF 10% 50V (AEP, SP, SP6, AUS, UK) CC09 1-162-282-31 CERAMIC 100PF 10% 50V (AEP, SP, SP6, AUS, UK) CC11 1-127-876-11 CERAMIC 0.01uF 10% 50V (AEP, SP, SP6, AUS, UK) CC13 1-127-876-11 CERAMIC 0.01uF 10% 50V (AEP, SP, SP6, AUS, UK) CC15 1-127-876-11 CERAMIC 0.01uF 10% 50V (AEP, SP, SP6, AUS, UK) CC17 1-127-876-11 CERAMIC 0.01uF 10% 50V (AEP, SP, SP6, AUS, UK) CC31 1-162-286-31 CERAMIC 220PF 10% 50V (AEP, SP, SP6, AUS, UK) CC32 1-162-286-31 CERAMIC 220PF 10% 50V (AEP, SP, SP6, AUS, UK) CC33 1-162-286-31 CERAMIC 220PF 10% 50V (AEP, SP, SP6, AUS, UK) CC34 1-162-286-31 CERAMIC 220PF 10% 50V (AEP, SP, SP6, AUS, UK) CC35 1-162-286-31 CERAMIC 220PF 10% 50V (AEP, SP, SP6, AUS, UK) CC36 1-162-286-31 CERAMIC 220PF 10% 50V (AEP, SP, SP6, AUS, UK) CC51 1-162-282-31 CERAMIC 100PF 10% 50V (AEP, SP, SP6, AUS, UK) CC52 1-162-282-31 CERAMIC 100PF 10% 50V (AEP, SP, SP6, AUS, UK) CC54 1-162-282-31 CERAMIC 100PF 10% 50V (AEP, SP, SP6, AUS, UK) CC55 1-162-282-31 CERAMIC 100PF 10% 50V (AEP, SP, SP6, AUS, UK) CC56 1-162-282-31 CERAMIC 100PF 10% 50V (AEP, SP, SP6, AUS, UK) CC57 1-162-282-31 CERAMIC 100PF 10% 50V (AEP, SP, SP6, AUS, UK) CC58 1-162-282-31 CERAMIC 100PF 10% 50V (AEP, SP, SP6, AUS, UK) CC59 1-162-282-31 CERAMIC 100PF 10% 50V (AEP, SP, SP6, AUS, UK) < CONNECTOR > CNP500 1-766-715-21 CONNECTOR, BOARD TO BOARD 10P CNP501 1-573-847-11 CONNECTOR, BOARD TO BOARD 15P CNP503 1-779-978-11 PIN, CONNECTOR 3P * CNP801 1-564-104-00 PIN, CONNECTOR (3.96mm PITCH) 3P CNP802 1-691-767-11 PLUG (MICRO CONNECTOR) 5P CNP806 1-779-978-11 PIN, CONNECTOR 3P CNP911 1-779-977-11 PIN, CONNECTOR 6P CNP912 1-691-766-11 PLUG (MICRO CONNECTOR) 4P CNP913 1-784-922-11 PIN, CONNECTOR 5P < DIODE > D505 8-719-991-33 DIODE 1SS133T-72 D529 8-719-991-33 DIODE 1SS133T-72 D540 8-719-991-33 DIODE 1SS133T-72 D560 8-719-991-33 DIODE 1SS133T-72 D580 8-719-991-33 DIODE 1SS133T-72 (K880) D585 8-719-991-33 DIODE 1SS133T-72 (K880) D605 8-719-991-33 DIODE 1SS133T-72 D610 8-719-991-33 DIODE 1SS133T-72 D640 8-719-991-33 DIODE 1SS133T-72 D665 8-719-991-33 DIODE 1SS133T-72 D680 8-719-991-33 DIODE 1SS133T-72 D690 8-719-934-21 DIODE HZS30-1LTA D691 8-719-991-33 DIODE 1SS133T-72 D692 8-719-991-33 DIODE 1SS133T-72 D693 8-719-934-21 DIODE HZS30-1LTA D705 8-719-991-33 DIODE 1SS133T-72 D710 8-719-991-33 DIODE 1SS133T-72 D721 8-719-991-33 DIODE 1SS133T-72 D722 8-719-991-33 DIODE 1SS133T-72 D729 8-719-991-33 DIODE 1SS133T-72 D732 8-719-991-33 DIODE 1SS133T-72 D740 8-719-991-33 DIODE 1SS133T-72 D749 8-719-991-33 DIODE 1SS133T-72 D750 8-719-991-33 DIODE 1SS133T-72 D765 8-719-991-33 DIODE 1SS133T-72 D791 8-719-991-33 DIODE 1SS133T-72 D801 8-719-933-95 DIODE HZS20-1LTA D802 8-719-072-05 DIODE RBV-602LF-A D804 8-719-068-28 DIODE HZ6.8BP-TK D805 6-500-522-11 DIODE 10EDB40-TA2B5 D806 6-500-522-11 DIODE 10EDB40-TA2B5 D807 6-500-522-11 DIODE 10EDB40-TA2B5 D808 6-500-522-11 DIODE 10EDB40-TA2B5 D841 8-719-981-96 DIODE MTZJ-3.0 D896 8-719-043-76 DIODE AK04V1 < IC > IC401 6-707-362-01 IC BD3451KS IC402 8-759-167-88 IC NJM4565D IC501 6-700-943-01 IC uPC2581V-S IC601 6-700-943-01 IC uPC2581V-S IC691 8-759-167-88 IC NJM4565D IC701 6-700-943-01 IC uPC2581V-S IC801 8-759-071-48 IC TA7807S IC802 8-759-071-47 IC TA79007S < JACK > J309 1-770-377-21 JACK, PIN 1P (AUDIO OUT/SUB WOOFER) J401 1-793-775-12 JACK, PIN 6P (MULTI CH IN) J402 1-770-614-11 JACK, PIN 4P (SA-CD/CD, MD/TAPE) J403 1-770-614-11 JACK, PIN 4P 4P (MD/TAPE, DVD) MAIN Ver. 1.1 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 61 STR-K880/K900 Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark J404 1-774-411-11 JACK, PIN 6P (VIDEO 1/VIDEO 2) < COIL > L601 1-420-872-52 COIL, AIR-CORE L651 1-420-872-52 COIL, AIR-CORE L701 1-420-872-52 COIL, AIR-CORE L751 1-420-872-52 COIL, AIR-CORE < TRANSISTOR > Q501 8-729-119-76 TRANSISTOR 2SA1115TP-EF Q502 8-729-141-30 TRANSISTOR 2SC3623ATP-LK Q505 8-729-042-09 TRANSISTOR 2SA1038S-RSE-TP Q506 8-729-042-09 TRANSISTOR 2SA1038S-RSE-TP Q535 8-729-042-09 TRANSISTOR 2SA1038S-RSE-TP (K880) Q536 8-729-042-09 TRANSISTOR 2SA1038S-RSE-TP (K880) Q540 8-729-281-53 TRANSISTOR 2SC1815GR-TPE2 Q560 8-729-119-78 TRANSISTOR 2SC1740S-QRT Q571 8-729-119-76 TRANSISTOR 2SA1115TP-EF (K880) Q572 8-729-141-30 TRANSISTOR 2SC3623ATP-LK (K880) Q580 8-729-281-53 TRANSISTOR 2SC1815GR-TPE2 (K880) Q601 8-729-119-76 TRANSISTOR 2SA1115TP-EF Q602 8-729-141-30 TRANSISTOR 2SC3623ATP-LK Q605 8-729-042-09 TRANSISTOR 2SA1038S-RSE-TP Q606 8-729-042-09 TRANSISTOR 2SA1038S-RSE-TP Q610 8-729-119-78 TRANSISTOR 2SC1740S-QRT Q640 8-729-281-53 TRANSISTOR 2SC1815GR-TPE2 Q651 8-729-119-76 TRANSISTOR 2SA1115TP-EF Q652 8-729-141-30 TRANSISTOR 2SC3623ATP-LK Q655 8-729-042-09 TRANSISTOR 2SA1038S-RSE-TP Q656 8-729-042-09 TRANSISTOR 2SA1038S-RSE-TP Q680 8-729-281-53 TRANSISTOR 2SC1815GR-TPE2 Q691 8-729-281-53 TRANSISTOR 2SC1815GR-TPE2 Q692 8-729-029-40 TRANSISTOR DTA124ESA-TP Q693 8-729-281-53 TRANSISTOR 2SC1815GR-TPE2 Q694 8-729-281-53 TRANSISTOR 2SC1815GR-TPE2 Q695 8-729-119-76 TRANSISTOR 2SA1115TP-EF Q701 8-729-119-76 TRANSISTOR 2SA1115TP-EF Q702 8-729-141-30 TRANSISTOR 2SC3623ATP-LK Q705 8-729-042-09 TRANSISTOR 2SA1038S-RSE-TP Q706 8-729-042-09 TRANSISTOR 2SA1038S-RSE-TP Q710 8-729-119-78 TRANSISTOR 2SC1740S-QRT Q722 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA Q723 8-729-119-78 TRANSISTOR 2SC1740S-QRT Q725 8-729-042-09 TRANSISTOR 2SA1038S-RSE-TP Q740 8-729-281-53 TRANSISTOR 2SC1815GR-TPE2 Q750 8-729-281-53 TRANSISTOR 2SC1815GR-TPE2 Q751 8-729-119-76 TRANSISTOR 2SA1115TP-EF Q752 8-729-141-30 TRANSISTOR 2SC3623ATP-LK Q755 8-729-042-09 TRANSISTOR 2SA1038S-RSE-TP Q756 8-729-042-09 TRANSISTOR 2SA1038S-RSE-TP Q790 8-729-119-78 TRANSISTOR 2SC1740S-QRT Q793 8-729-119-78 TRANSISTOR 2SC1740S-QRT Q795 8-729-042-09 TRANSISTOR 2SA1038S-RSE-TP Q801 8-729-140-97 TRANSISTOR 2SB734-T-34 < RESISTOR > R402 1-247-831-91 CARBON 1K 5% 1/4W R404 1-247-831-91 CARBON 1K 5% 1/4W R405 1-247-831-91 CARBON 1K 5% 1/4W R406 1-247-831-91 CARBON 1K 5% 1/4W R407 1-247-831-91 CARBON 1K 5% 1/4W R408 1-247-831-91 CARBON 1K 5% 1/4W R409 1-247-831-91 CARBON 1K 5% 1/4W R428 1-247-831-91 CARBON 1K 5% 1/4W R429 1-247-831-91 CARBON 1K 5% 1/4W R431 1-247-831-91 CARBON 1K 5% 1/4W R432 1-247-831-91 CARBON 1K 5% 1/4W R433 1-247-831-91 CARBON 1K 5% 1/4W R434 1-247-831-91 CARBON 1K 5% 1/4W R435 1-247-831-91 CARBON 1K 5% 1/4W R436 1-247-831-91 CARBON 1K 5% 1/4W R452 1-247-831-91 CARBON 1K 5% 1/4W R454 1-247-831-91 CARBON 1K 5% 1/4W R455 1-247-831-91 CARBON 1K 5% 1/4W R456 1-247-831-91 CARBON 1K 5% 1/4W R457 1-247-831-91 CARBON 1K 5% 1/4W R458 1-247-831-91 CARBON 1K 5% 1/4W R459 1-247-831-91 CARBON 1K 5% 1/4W R468 1-247-879-91 CARBON 100K 5% 1/4W R469 1-247-831-91 CARBON 1K 5% 1/4W R470 1-247-871-91 CARBON 47K 5% 1/4W R473 1-249-429-11 CARBON 10K 5% 1/4W R474 1-249-429-11 CARBON 10K 5% 1/4W R475 1-249-429-11 CARBON 10K 5% 1/4W R476 1-249-429-11 CARBON 10K 5% 1/4W R480 1-247-871-91 CARBON 47K 5% 1/4W R499 1-247-871-91 CARBON 47K 5% 1/4W R501 1-247-831-91 CARBON 1K 5% 1/4W R502 1-249-439-11 CARBON 68K 5% 1/4W R503 1-249-421-11 CARBON 2.2K 5% 1/4W R505 1-249-439-11 CARBON 68K 5% 1/4W R510 1-249-421-11 CARBON 2.2K 5% 1/4W R511 1-249-440-11 CARBON 82K 5% 1/4W R513 1-249-414-11 CARBON 560 5% 1/4W 0R514 1-249-399-11 CARBON 33 5% 1/4W 0R515 1-249-399-11 CARBON 33 5% 1/4W 0R516 1-234-182-11 ENCAPSULATED COMPONENT 0R517 1-249-393-11 CARBON 10 5% 1/4W R520 1-247-847-91 CARBON 4.7K 5% 1/4W 0R521 1-240-855-81 CARBON 6.2K 5% 1/4W R522 1-249-419-11 CARBON 1.5K 5% 1/4W R523 1-247-871-91 CARBON 47K 5% 1/4W (K880) R524 1-249-431-11 CARBON 15K 5% 1/4W R525 1-249-439-11 CARBON 68K 5% 1/4W 0R526 1-234-182-11 ENCAPSULATED COMPONENT (K880) R529 1-249-429-11 CARBON 10K 5% 1/4W R530 1-247-847-91 CARBON 4.7K 5% 1/4W (K880) 0R531 1-240-855-81 CARBON 6.2K 5% 1/4W R532 1-249-429-11 CARBON 10K 5% 1/4W R533 1-247-871-91 CARBON 47K 5% 1/4W R534 1-249-431-11 CARBON 15K 5% 1/4W (K880) R535 1-249-439-11 CARBON 68K 5% 1/4W (K880) MAIN www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 62 STR-K880/K900 Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 0R537 1-249-393-11 CARBON 10 5% 1/4W (K880) R539 1-247-879-91 CARBON 100K 5% 1/4W R540 1-247-863-91 CARBON 22K 5% 1/4W R546 1-249-431-11 CARBON 15K 5% 1/4W R553 1-249-421-11 CARBON 2.2K 5% 1/4W (K880) R554 1-249-439-11 CARBON 68K 5% 1/4W (K880) R555 1-247-847-91 CARBON 4.7K 5% 1/4W R556 1-247-871-91 CARBON 47K 5% 1/4W R557 1-249-431-11 CARBON 15K 5% 1/4W R561 1-247-831-91 CARBON 1K 5% 1/4W (K880) R562 1-249-439-11 CARBON 68K 5% 1/4W (K880) R570 1-249-421-11 CARBON 2.2K 5% 1/4W (K880) R571 1-249-440-11 CARBON 82K 5% 1/4W (K880) R572 1-249-419-11 CARBON 1.5K 5% 1/4W (K880) R573 1-247-871-91 CARBON 47K 5% 1/4W 0R574 1-249-399-11 CARBON 33 5% 1/4W (K880) 0R575 1-249-399-11 CARBON 33 5% 1/4W (K880) R576 1-249-414-11 CARBON 560 5% 1/4W R580 1-247-863-91 CARBON 22K 5% 1/4W (K880) R585 1-247-847-91 CARBON 4.7K 5% 1/4W (K880) R586 1-247-871-91 CARBON 47K 5% 1/4W (K880) R587 1-249-431-11 CARBON 15K 5% 1/4W (K880) R588 1-249-431-11 CARBON 15K 5% 1/4W (K880) R601 1-247-831-91 CARBON 1K 5% 1/4W R602 1-249-439-11 CARBON 68K 5% 1/4W R603 1-249-421-11 CARBON 2.2K 5% 1/4W R604 1-249-439-11 CARBON 68K 5% 1/4W R610 1-249-421-11 CARBON 2.2K 5% 1/4W R611 1-249-440-11 CARBON 82K 5% 1/4W R613 1-249-414-11 CARBON 560 5% 1/4W 0R614 1-249-399-11 CARBON 33 5% 1/4W 0R615 1-249-399-11 CARBON 33 5% 1/4W 0R616 1-234-182-11 ENCAPSULATED COMPONENT 0R617 1-249-393-11 CARBON 10 5% 1/4W 0R618 1-249-389-11 CARBON 4.7 5% 1/4W R620 1-247-847-91 CARBON 4.7K 5% 1/4W 0R621 1-240-855-81 CARBON 6.2K 5% 1/4W (K880) R622 1-249-419-11 CARBON 1.5K 5% 1/4W R623 1-247-871-91 CARBON 47K 5% 1/4W R624 1-249-431-11 CARBON 15K 5% 1/4W R625 1-249-439-11 CARBON 68K 5% 1/4W R631 1-249-421-11 CARBON 2.2K 5% 1/4W 0R634 1-249-404-00 CARBON 82 5% 1/4W R638 1-249-439-11 CARBON 68K 5% 1/4W R640 1-247-863-91 CARBON 22K 5% 1/4W R648 1-249-431-11 CARBON 15K 5% 1/4W R651 1-247-831-91 CARBON 1K 5% 1/4W R652 1-249-439-11 CARBON 68K 5% 1/4W R653 1-249-421-11 CARBON 2.2K 5% 1/4W R654 1-249-439-11 CARBON 68K 5% 1/4W R655 1-247-847-91 CARBON 4.7K 5% 1/4W R656 1-247-871-91 CARBON 47K 5% 1/4W R657 1-249-431-11 CARBON 15K 5% 1/4W R660 1-249-421-11 CARBON 2.2K 5% 1/4W R661 1-249-440-11 CARBON 82K 5% 1/4W R663 1-249-414-11 CARBON 560 5% 1/4W 0R664 1-249-399-11 CARBON 33 5% 1/4W 0R665 1-249-399-11 CARBON 33 5% 1/4W 0R666 1-234-182-11 ENCAPSULATED COMPONENT 0R667 1-249-393-11 CARBON 10 5% 1/4W 0R668 1-249-389-11 CARBON 4.7 5% 1/4W R669 1-247-847-91 CARBON 4.7K 5% 1/4W 0R671 1-240-855-81 CARBON 6.2K 5% 1/4W R672 1-249-419-11 CARBON 1.5K 5% 1/4W R673 1-247-871-91 CARBON 47K 5% 1/4W R674 1-249-431-11 CARBON 15K 5% 1/4W R675 1-247-847-91 CARBON 4.7K 5% 1/4W R676 1-247-871-91 CARBON 47K 5% 1/4W R677 1-249-431-11 CARBON 15K 5% 1/4W R680 1-247-863-91 CARBON 22K 5% 1/4W R681 1-249-431-11 CARBON 15K 5% 1/4W R689 1-249-429-11 CARBON 10K 5% 1/4W R690 1-247-887-00 CARBON 220K 5% 1/4W R691 1-215-888-00 METAL OXIDE 220 5% 2W R692 1-215-889-00 METAL OXIDE 330 5% 2W R693 1-249-429-11 CARBON 10K 5% 1/4W R694 1-249-429-11 CARBON 10K 5% 1/4W R695 1-249-429-11 CARBON 10K 5% 1/4W R696 1-247-871-91 CARBON 47K 5% 1/4W R697 1-247-871-91 CARBON 47K 5% 1/4W R698 1-249-429-11 CARBON 10K 5% 1/4W R699 1-247-895-00 CARBON 470K 5% 1/4W R700 1-249-429-11 CARBON 10K 5% 1/4W R701 1-247-831-91 CARBON 1K 5% 1/4W R702 1-249-439-11 CARBON 68K 5% 1/4W R703 1-249-421-11 CARBON 2.2K 5% 1/4W R704 1-249-439-11 CARBON 68K 5% 1/4W R705 1-247-895-00 CARBON 470K 5% 1/4W R706 1-215-888-00 METAL OXIDE 220 5% 2W R710 1-249-421-11 CARBON 2.2K 5% 1/4W R711 1-249-440-11 CARBON 82K 5% 1/4W R713 1-249-414-11 CARBON 560 5% 1/4W 0R714 1-249-399-11 CARBON 33 5% 1/4W 0R715 1-249-399-11 CARBON 33 5% 1/4W 0R716 1-234-182-11 ENCAPSULATED COMPONENT 0R717 1-249-393-11 CARBON 10 5% 1/4W 0R718 1-249-389-11 CARBON 4.7 5% 1/4W R719 1-247-847-91 CARBON 4.7K 5% 1/4W 0R721 1-240-855-81 CARBON 6.2K 5% 1/4W R722 1-249-419-11 CARBON 1.5K 5% 1/4W R723 1-247-871-91 CARBON 47K 5% 1/4W R724 1-249-431-11 CARBON 15K 5% 1/4W MAIN www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 63 STR-K880/K900 Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark R725 1-249-439-11 CARBON 68K 5% 1/4W R729 1-249-429-11 CARBON 10K 5% 1/4W R731 1-249-421-11 CARBON 2.2K 5% 1/4W 0R732 1-249-381-11 CARBON 1 5% 1/4W 0R733 1-249-381-11 CARBON 1 5% 1/4W 0R734 1-249-404-00 CARBON 82 5% 1/4W R735 1-249-427-11 CARBON 6.8K 5% 1/4W R736 1-247-831-91 CARBON 1K 5% 1/4W R737 1-249-436-11 CARBON 39K 5% 1/4W R739 1-247-879-91 CARBON 100K 5% 1/4W R740 1-247-863-91 CARBON 22K 5% 1/4W R741 1-249-431-11 CARBON 15K 5% 1/4W R743 1-249-431-11 CARBON 15K 5% 1/4W R744 1-249-431-11 CARBON 15K 5% 1/4W R745 1-247-847-91 CARBON 4.7K 5% 1/4W R746 1-247-871-91 CARBON 47K 5% 1/4W R747 1-249-431-11 CARBON 15K 5% 1/4W R748 1-249-431-11 CARBON 15K 5% 1/4W R749 1-249-429-11 CARBON 10K 5% 1/4W R750 1-247-863-91 CARBON 22K 5% 1/4W R751 1-247-831-91 CARBON 1K 5% 1/4W R752 1-249-439-11 CARBON 68K 5% 1/4W R753 1-249-421-11 CARBON 2.2K 5% 1/4W R754 1-249-439-11 CARBON 68K 5% 1/4W R755 1-247-847-91 CARBON 4.7K 5% 1/4W R756 1-247-871-91 CARBON 47K 5% 1/4W R757 1-249-431-11 CARBON 15K 5% 1/4W R758 1-249-431-11 CARBON 15K 5% 1/4W R759 1-247-879-91 CARBON 100K 5% 1/4W R760 1-249-421-11 CARBON 2.2K 5% 1/4W R761 1-249-440-11 CARBON 82K 5% 1/4W R763 1-249-414-11 CARBON 560 5% 1/4W 0R764 1-249-399-11 CARBON 33 5% 1/4W 0R765 1-249-399-11 CARBON 33 5% 1/4W 0R766 1-234-182-11 ENCAPSULATED COMPONENT 0R767 1-249-393-11 CARBON 10 5% 1/4W 0R768 1-249-389-11 CARBON 4.7 5% 1/4W R769 1-247-847-91 CARBON 4.7K 5% 1/4W 0R771 1-240-855-81 CARBON 6.2K 5% 1/4W R772 1-249-419-11 CARBON 1.5K 5% 1/4W R773 1-247-871-91 CARBON 47K 5% 1/4W R775 1-249-439-11 CARBON 68K 5% 1/4W R778 1-249-431-11 CARBON 15K 5% 1/4W R780 1-249-429-11 CARBON 10K 5% 1/4W R791 1-249-421-11 CARBON 2.2K 5% 1/4W R792 1-215-868-00 METAL OXIDE 680 5% 1W 0R793 1-249-404-00 CARBON 82 5% 1/4W R794 1-215-868-00 METAL OXIDE 680 5% 1W 0R802 1-249-409-11 CARBON 220 5% 1/4W 0R803 1-249-389-11 CARBON 4.7 5% 1/4W R804 1-249-429-11 CARBON 10K 5% 1/4W R806 1-247-863-91 CARBON 22K 5% 1/4W R840 1-249-427-11 CARBON 6.8K 5% 1/4W R844 1-247-863-91 CARBON 22K 5% 1/4W 0R910 1-240-877-11 FUSIBLE 0.15 5% 1/2W 0RR11 1-249-393-11 CARBON 10 5% 1/4W (AEP, SP, SP6, AUS, UK) 0RR12 1-249-393-11 CARBON 10 5% 1/4W (AEP, SP, SP6, AUS, UK) 0RR13 1-249-393-11 CARBON 10 5% 1/4W (AEP, SP, SP6, AUS, UK) 0RR14 1-249-393-11 CARBON 10 5% 1/4W (AEP, SP, SP6, AUS, UK) < RELAY > RY560 1-755-267-11 RELAY RY601 1-755-170-11 RELAY (12V) RY701 1-755-170-11 RELAY (12V) RY791 1-755-170-11 RELAY (12V) < TERMINAL > TM601 1-780-364-11 TERMINAL BOARD (SP) (8P) (SPEAKERS SURROUND/FRONT A) ************************************************************* POWER BOARD ************* < RESISTOR > R114 1-247-831-91 CARBON 1K 5% 1/4W < SWITCH > S100 1-771-410-21 SWITCH, TACTILE (?/1) S115 1-771-410-21 SWITCH, TACTILE (SPEAKERS (OFF/A/B/A+B)) ************************************************************* SPEAKER BOARD (K880) ************** < CAPACITOR > CC16 1-127-876-11 CERAMIC 0.01uF 10% 50V (K880) CC17 1-127-876-11 CERAMIC 0.01uF 10% 50V (K880) < CONNECTOR > * CNP503 1-564-241-11 PIN, CONNECTOR (3.96mm PITCH) 4P < DIODE > D510 8-719-991-33 DIODE 1SS133T-72 < COIL > L571 1-420-872-52 COIL, AIR-CORE L751 1-420-872-52 COIL, AIR-CORE < TRANSISTOR > Q550 8-729-119-78 TRANSISTOR 2SC1740S-QRT < RESISTOR > R531 1-249-421-11 CARBON 2.2K 5% 1/4W 0R534 1-249-404-00 CARBON 82 5% 1/4W 0R578 1-249-389-11 CARBON 4.7 5% 1/4W 0R751 1-249-389-11 CARBON 4.7 5% 1/4W 0RR16 1-249-393-11 CARBON 10 5% 1/4W (K880) POWER MAIN SPEAKER Ver. 1.1 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 64 STR-K880/K900 Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 0RR17 1-249-393-11 CARBON 10 5% 1/4W (K880) < RELAY > RY501 1-755-170-11 RELAY (12V) < TERMINAL > TM501 1-780-217-11 TERMINAL BOARD (SP) (2P) (CENTER) (K900) TM501 1-780-365-11 TERMINAL BOARD (SP) (4P) (CENTER/SURROUND BACK)(K880) ************************************************************* SPEAKER B BOARD *************** < CAPACITOR > CC20 1-127-876-11 CERAMIC 0.01uF 10% 50V (AEP, SP, SP6, AUS, UK) CC21 1-127-876-11 CERAMIC 0.01uF 10% 50V (AEP, SP, SP6, AUS, UK) < CONNECTOR > CNP600 1-785-103-11 PIN, CONNECTOR (3.96mm PITCH) 5P CNP601 1-784-921-11 PIN, CONNECTOR 4P * CNP807 1-564-242-00 PIN, CONNECTOR (3.96mm PITCH) 5P < DIODE > D800 8-719-991-33 DIODE 1SS133T-72 D818 8-719-991-33 DIODE 1SS133T-72 < TRANSISTOR > Q800 8-729-119-78 TRANSISTOR 2SC1740S-QRT Q809 8-729-119-78 TRANSISTOR 2SC1740S-QRT < RESISTOR > 0R800 1-249-404-00 CARBON 82 5% 1/4W R812 1-249-421-11 CARBON 2.2K 5% 1/4W R824 1-249-421-11 CARBON 2.2K 5% 1/4W (US, CND, E51) 0R830 1-249-401-81 CARBON 47 5% 1/4W (CND) 0R831 1-249-401-81 CARBON 47 5% 1/4W R8124 1-249-421-11 CARBON 2.2K 5% 1/4W (AEP, SP, SP6, AUS, UK) 0RR20 1-249-393-11 CARBON 10 5% 1/4W (AEP, SP, SP6, AUS, UK) 0RR21 1-249-393-11 CARBON 10 5% 1/4W (AEP, SP, SP6, AUS, UK) < RELAY > RY600 1-755-170-11 RELAY (12V) RY801 1-755-013-11 RELAY (EXCEPT CND) RY802 1-755-520-11 RELAY (CND) RY803 1-755-520-11 RELAY (CND) < TERMINAL > TM602 1-537-240-11 TERMINAL BOARD (CHECKER PIN) (FRONT B) ************************************************************* STANDBY BOARD ************* < CAPACITOR > C913 1-127-888-11 CERAMIC 0.1uF 10% 50V C914 1-127-888-11 CERAMIC 0.1uF 10% 50V C915 1-126-943-11 ELECT 2200uF 20% 25V C916 1-126-942-61 ELECT 1000uF 20% 25V C920 1-127-888-11 CERAMIC 0.1uF 10% 50V C921 1-127-888-11 CERAMIC 0.1uF 10% 50V C924 1-126-960-11 ELECT 1uF 20% 50V C950 1-126-936-11 ELECT 3300uF 20% 16V < CONNECTOR > CNP801 1-784-922-11 PIN, CONNECTOR 5P CNP804 1-564-506-11 PLUG, CONNECTOR 3P CNP901 1-564-321-00 PIN, CONNECTOR (3.96mm PITCH) 2P CNP902 1-794-577-21 PIN, CONNECTOR (POWER) CNP903 1-779-977-11 PIN, CONNECTOR 6P CNP906 1-568-106-11 PIN, CONNECTOR (3.96mm PITCH) 4P (E51) < DIODE > D901 8-719-991-33 DIODE 1SS133T-72 D910 6-500-522-11 DIODE 10EDB40-TA2B5 D911 6-500-522-11 DIODE 10EDB40-TA2B5 D912 6-500-522-11 DIODE 10EDB40-TA2B5 D913 6-500-522-11 DIODE 10EDB40-TA2B5 D914 8-719-991-33 DIODE 1SS133T-72 D915 8-719-991-33 DIODE 1SS133T-72 D920 6-500-522-11 DIODE 10EDB40-TA2B5 D921 6-500-522-11 DIODE 10EDB40-TA2B5 D922 6-500-522-11 DIODE 10EDB40-TA2B5 D923 6-500-522-11 DIODE 10EDB40-TA2B5 < FUSE HOLDER > FH901 1-533-217-41 HOLDER, FUSE FH951 1-533-217-41 HOLDER, FUSE < GROUND TERMINAL > G901 1-537-738-21 TERMINAL, GROUND < TRANSISTOR > Q901 8-729-119-78 TRANSISTOR 2SC1740S-QRT Q921 8-729-119-78 TRANSISTOR 2SC1740S-QRT < RESISTOR > 0R810 1-243-634-91 FUSIBLE 0.22 5% 1/2W 0R811 1-243-634-91 FUSIBLE 0.22 5% 1/2W 0R901 1-219-237-91 SOLID 3.3M 20% 1/2W (K900) R902 1-247-871-91 CARBON 47K 5% 1/4W R903 1-249-421-11 CARBON 2.2K 5% 1/4W R904 1-249-381-11 CARBON 1 5% 1/4W R921 1-247-871-91 CARBON 47K 5% 1/4W R922 1-247-863-91 CARBON 22K 5% 1/4W R923 1-249-429-11 CARBON 10K 5% 1/4W SPEAKER SPEAKER B STANDBY Ver. 1.1 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 65 STR-K880/K900 Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark < RELAY > 0RY901 1-755-541-11 RELAY < TRANSFORMER > T902 1-443-516-11 POWER TRANSFORMER (K900) T902 1-443-517-11 POWER TRANSFORMER (AEP, SP, SP6, AUS, UK) T902 1-443-520-11 POWER TRANSFORMER (E51) ************************************************************* VIDEO BOARD *********** < CAPACITOR > C200 1-128-805-11 CERAMIC 47PF 5% 50V C201 1-128-805-11 CERAMIC 47PF 5% 50V C206 1-126-964-11 ELECT 10uF 20% 50V C207 1-126-964-11 ELECT 10uF 20% 50V C208 1-126-964-11 ELECT 10uF 20% 50V C209 1-126-964-11 ELECT 10uF 20% 50V C210 1-126-964-11 ELECT 10uF 20% 50V C213 1-126-934-11 ELECT 220uF 20% 16V C214 1-127-888-11 CERAMIC 0.1uF 10% 50V C215 1-127-888-11 CERAMIC 0.1uF 10% 50V C220 1-126-947-11 ELECT 47uF 20% 25V C221 1-126-934-11 ELECT 220uF 20% 16V C223 1-127-888-11 CERAMIC 0.1uF 10% 50V C224 1-127-888-11 CERAMIC 0.1uF 10% 50V C308 1-126-964-11 ELECT 10uF 20% 50V C309 1-126-964-11 ELECT 10uF 20% 50V C310 1-126-964-11 ELECT 10uF 20% 50V C311 1-126-964-11 ELECT 10uF 20% 50V C312 1-126-964-11 ELECT 10uF 20% 50V C313 1-126-964-11 ELECT 10uF 20% 50V C314 1-127-868-11 CERAMIC 2200PF 10% 50V C315 1-127-868-11 CERAMIC 2200PF 10% 50V C316 1-127-868-11 CERAMIC 2200PF 10% 50V C317 1-126-947-11 ELECT 47uF 20% 25V C330 1-127-888-11 CERAMIC 0.1uF 10% 50V C331 1-127-888-11 CERAMIC 0.1uF 10% 50V C338 1-126-947-11 ELECT 47uF 20% 25V < CONNECTOR > CNP202 1-564-705-11 PIN, CONNECTOR (SMALL TYPE) 3P CNP203 1-691-765-11 PLUG (MICRO CONNECTOR) 3P CNS250 1-784-778-11 CONNECTOR, FFC 17P < DIODE > D203 8-719-991-33 DIODE 1SS133T-72 D204 8-719-991-33 DIODE 1SS133T-72 < IC > IC203 6-701-890-01 IC NJM2595D IC304 6-707-363-01 IC NJM2586AL IC804 8-759-245-79 IC TA79005S IC807 8-759-231-53 IC TA7805S < JACK > J200 1-794-978-11 JACK, PIN 3P (VIDEO 1/ VIDEO 2/ DVD) J201 1-815-043-11 JACK, PIN 2P (VIDEO 1/ MONITOR) J301 1-816-592-11 JACK, PIN 9P (COMPONENT VIDEO) < RESISTOR > R200 1-247-804-11 CARBON 75 5% 1/4W R201 1-247-804-11 CARBON 75 5% 1/4W R218 1-247-804-11 CARBON 75 5% 1/4W R219 1-247-804-11 CARBON 75 5% 1/4W R220 1-247-804-11 CARBON 75 5% 1/4W R221 1-247-804-11 CARBON 75 5% 1/4W R301 1-247-804-11 CARBON 75 5% 1/4W R302 1-247-804-11 CARBON 75 5% 1/4W R303 1-247-804-11 CARBON 75 5% 1/4W R304 1-247-804-11 CARBON 75 5% 1/4W R305 1-247-804-11 CARBON 75 5% 1/4W R306 1-247-804-11 CARBON 75 5% 1/4W R307 1-247-804-11 CARBON 75 5% 1/4W R308 1-247-804-11 CARBON 75 5% 1/4W R309 1-247-804-11 CARBON 75 5% 1/4W R310 1-247-831-91 CARBON 1K 5% 1/4W R311 1-247-831-91 CARBON 1K 5% 1/4W R312 1-247-831-91 CARBON 1K 5% 1/4W R313 1-247-863-91 CARBON 22K 5% 1/4W ************************************************************* VIDEO 3 BOARD ************* < CAPACITOR > C293 1-127-888-11 CERAMIC 0.1uF 10% 50V C294 1-127-888-11 CERAMIC 0.1uF 10% 50V < CONNECTOR > CN201 1-784-922-11 PIN, CONNECTOR 5P < JACK > J298 1-819-187-11 PIN JACK 3P (VIDEO 3 IN/ PORTABLE AV IN) < RESISTOR > R298 1-247-831-91 CARBON 1K 5% 1/4W R299 1-247-831-91 CARBON 1K 5% 1/4W < LEAD > * W290 1-690-880-31 LEAD (WITH CONNECTOR) ************************************************************* MISCELLANEOUS ************** 057 1-696-847-11 CORD, POWER (AUS) 057 1-777-071-22 CORD, POWER (E51) 057 1-777-071-82 CORD, POWER (AEP, SP, SP6, UK) 057 1-783-532-11 CORD, POWER (US, CND) 59 1-828-993-11 WIRE (FLAT TYPE) (17 CORE) 60 1-828-963-11 WIRE (FLAT TYPE) (11 CORE)(EXCEPT AEP, UK) STANDBY VIDEO VIDEO 3 Ver. 1.1 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 66 STR-K880/K900 Ref. No. Part No. Description Remark 60 1-828-980-11 WIRE (FLAT TYPE) (15 CORE) (AEP, UK) 0F901 1-532-464-33 FUSE (T2.5AL/250V) (K880) 0F901 1-576-109-11 FUSE (5A/125V)(K900) Q503 6-702-390-01 IC MN2488-OPY-MK Q504 6-702-391-01 IC MP1620-OPY-MK Q533 6-702-390-01 IC MN2488-OPY-MK (K880) Q534 6-702-391-01 IC MP1620-OPY-MK (K880) Q603 6-702-390-01 IC MN2488-OPY-MK Q604 6-702-391-01 IC MP1620-OPY-MK Q653 6-702-390-01 IC MN2488-OPY-MK Q654 6-702-391-01 IC MP1620-OPY-MK Q703 6-702-390-01 IC MN2488-OPY-MK Q704 6-702-391-01 IC MP1620-OPY-MK Q753 6-702-390-01 IC MN2488-OPY-MK Q754 6-702-391-01 IC MP1620-OPY-MK 0T901 1-443-524-11 POWER TRANSFORMER (CND, US) 0T901 1-443-525-11 POWER TRANSFORMER (AEP, SP, SP6, AUS, UK) 0T901 1-443-526-11 POWER TRANSFORMER (E51) TN1 1-693-675-11 TUNER (CND, E51, US) TN1 1-693-676-21 TUNER (AEP, UK) TN1 1-693-678-11 TUNER (SP, SP6, AUS) Ver. 1.1 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 67 STR-K880/K900 MEMO www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com STR-K880/K900 REVISION HISTORY Clicking the version allows you to jump to the revised page. Also, clicking the version at the upper right on the revised page allows you to jump to the next revised page. Ver. Date Description of Revision 1.0 2006.02 New 1.1 2006.05 Addition of SP6 model (Singapore and Malaysia models) for STR-K880 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com
