MICROFILM SERVICE MANUAL MINI Hi-Fi COMPONENT SYSTEM HCD-GRX70/GRX70J/RXD80 Dolby noise reduction manufactured under license from Dolby Laboratories Licensing Corporation. “DOLBY” and the double-D symbol a are trade- marks of Dolby Laboratories Licensing Corporation. Canadian Model HCD-RXD80 E Model HCD-GRX70/GRX70J Australian Model HCD-GRX70 HCD-GRX70/GRX70J/RXD80 are the Am- plifier, CD player, Tape Deck and Tuner section in HMC-GRX70/GRX70J/RXD80. SPECIFICATIONS Amplifier section Canadian model: Continuous RMS power output (reference) 100 + 100 watts (8 ohms at 1 kHz, 10% THD) Total harmonic distortion less than 0.07% (8 ohms at 1 kHz, 55 W) Other models: The following measured at AC 120, 220, 240 V 50/60 Hz DIN power output (rated) 130 + 130 watts (6 ohms at 1 kHz, DIN) Continuous RMS power output (reference) 170 + 170 watts (6 ohms at 1 kHz, 10% THD) Model Name Using Similar Mechanism HCD-GRX50/RXD7 CD Mechanism Type CDM38LH-5BD32L Base Unit Name BU-5BD32L Optical Pick-up Name KSS-213D/Q-NP Model Name Using Similar Mechanism HCD-GRX50/RXD7 Tape Transport Mechanism Type TCM-230AWR2 CD Section Tape deck Section Photo: HCD-GRX70 (GRAY) Inputs MD/VIDEO (AUDIO) IN: voltage 450 mV/250 mV, (phono jacks) impedance 47 kilohms MIX MIC: (phone jack) sensitivity 1 mV, impedance 10 kilohms Outputs MD OUT: voltage 250 mV, (phono jacks) impedance 1 kilohms PHONES: accepts headphones of 8 ohms (stereo mini jack) or more SPEAKER: Canadian model: accepts impedance of 8 to 16 ohms SURROUND SPEAKER (GRX70/GRX70J): accepts impedance of 16 ohms SUPER WOOFER: Voltage 1 V, impedance 1 kilohm – Continued on next page – www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 2 – Specifications (continued) CD player section System Compact disc and digital audio system Laser Semiconductor laser (λ=780nm) Emission duration: continuous Laser output Max. 44.6 µW* *This output is the value measured at distance of 200 mm from the objective lens surface on the Optical Pick-up Block with 7 mm aperture. Frequency response 2 Hz - 20 kHz (±0.5 dB) Wavelength 780 -790 nm Signal-to-noise ratio More than 90 dB Dynamic range More than 90 dB CD OPTICAL DIGITAL OUT (Square optical connector jack, rear panel) Wavelength 600 nm Output Level -18 dBm Tape player section Recording system 4-track 2-channel stereo Frequency response 40 - 13,000 Hz (±3 dB), (DOLBY NR OFF) using Sony TYPE I cassette 40 - 14,000 Hz (±3 dB), using Sony TYPE II cassette Tuner section FM stereo, FM/AM superheterodyne tuner FM tuner section Tuning range 87.5 - 108.0 MHz Antenna FM lead antenna Antenna terminals 75 ohm unbalanced Intermediate frequency 10.7 MHz UKV tuner section (3 band (FM-AM-UKV) models only) Tuning range 65.0 - 74.0 MHz Stereo Plus AM tuner section Tuning range 2 Band type: Canadian model: 530 - 1,710 kHz (with the interval set at 10 kHz) 531 - 1,710 kHz (with the interval set at 9 kHz) Other models: 531 - 1,602 kHz (with the interval set at 9 kHz) 530 - 1,710 kHz (with the interval set at 10 kHz) 3 Band type: Middle Eastern models: MW: 531 - 1,602 kHz (with the interval set at 9 kHz) SW: 5.95 - 17.90 MHz (with the interval set at 5 kHz) Other models: MW: 531 - 1,602 kHz (with the interval set at 9 kHz) 530 - 1,710 kHz (with the interval set at 10 kHz) SW: 5.95 - 17.90 MHz (with the interval set at 5 kHz) Antenna AM loop antenna Antenna terminals External antenna terminal Intermediate frequency 450 kHz General Power requirements Canadian model: 120 V AC, 60 Hz Mexican model: 120 V AC, 50/60 Hz Australian model: 230 - 240 V AC, 50/60 Hz Thai model: 220 V AC, 50/60 Hz Other models: 120 V, 220 V, or 230 - 240 V AC, 50/60 Hz Adjustable with voltage selector Power consumption 170 watts Dimensions (w/h/d) Approx. 280 × 340 × 395 mm (111/8 × 131/2 × 155/8 in.) Mass Canadian model: Approx. 10.2 kg Other models: Approx. 10.6 kg Supplied accessories: AM loop antenna (1) Remote Commander (1) Batteries (2) FM lead antenna (1) Speaker cords (2) Front speaker pads (8) Design and specifications are subject to change without notice. ATTENTION AU COMPOSANT AYANT RAPPORT À LA SÉCURITÉ! LES COMPOSANTS IDENTIFIÉS PAR UNE MARQUE ! SUR LES DIAGRAMMES SCHÉMATIQUES ET LA LISTE DES PIÈCES SONT CRITIQUES POUR LA SÉCURITÉ DE FONCTIONNEMENT. NE REMPLACER CES COM- POSANTS QUE PAR DES PIÈCES SONY DONT LES NUMÉROS SONT DONNÉS DANS CE MANUEL OU DANS LES SUPPLÉMENTS PUBLIÉS PAR SONY. SAFETY-RELATED COMPONENT WARNING!! COMPONENTS IDENTIFIED BY MARK ! OR DOTTED LINE WITH MARK ! ON THE SCHEMATIC DIAGRAMS AND IN THE PARTS LIST ARE CRITICAL TO SAFE OPERATION. REPLACE THESE COMPONENTS WITH SONY PARTS WHOSE PART NUMBERS APPEAR AS SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUB- LISHED BY SONY. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 3 – 1. SERVICING NOTES ............................................... 3 2. GENERAL Location of Controls ....................................................... 6 Setting the Time .............................................................. 7 3. DISASSEMBLY ......................................................... 8 4. TEST MODE .............................................................. 11 5. MECHANICAL ADJUSTMENTS ....................... 14 6. ELECTRICAL ADJUSTMENTS DECK Section ................................................................. 14 CD Section ...................................................................... 17 7. DIAGRAMS 7-1. Block Diagram – CD SERVO Section – ........................ 19 7-2. Block Diagram – TAPE DECK Section – ...................... 21 7-3. Block Diagram – MAIN Section – ................................. 23 7-4. Block Diagram – DISPLAY/KEY CONTROL/ POWER SUPPLY Section – ........................................... 25 7-5. Note for Printed Wiring Boards and Schematic Diagrams ....................................................... 27 7-6. Printed Wiring Board – BD Board – .............................. 29 7-7. Schematic Diagram – BD Board – ................................ 31 7-8. Printed Wiring Boards – CD MOTOR Section – .......... 33 7-9. Schematic Diagram – CD MOTOR Section – .............. 35 7-10. Printed Wiring Board – AUDIO Board – ...................... 37 7-11. Schematic Diagram – AUDIO Board – ......................... 39 7-12. Printed Wiring Board – LEAF SW Board – .................. 41 7-13. Schematic Diagram – LEAF SW Board –..................... 41 7-14. Printed Wiring Board – MAIN Board – ........................ 43 7-15. Schematic Diagram – MAIN Board (1/4) – ................. 45 7-16. Schematic Diagram – MAIN Board (2/4) – .................. 47 7-17. Schematic Diagram – MAIN Board (3/4) – .................. 49 7-18. Schematic Diagram – MAIN Board (4/4) – .................. 51 7-19. Printed Wiring Board – PANEL Board – ...................... 53 7-20. Schematic Diagram – PANEL Board – ......................... 55 7-21. Printed Wiring Board – CD SW Board – ...................... 57 7-22. Schematic Diagram – CD SW Board – ......................... 58 7-23. Printed Wiring Boards – TRANSFORMER Section – ........................................ 61 7-24. Schematic Diagram – TRANSFORMER Section – ........................................ 63 7-25. IC Pin Function Description ........................................... 67 8. EXPLODED VIEWS ................................................ 72 9. ELECTRICAL PARTS LIST ............................... 81 TABLE OF CONTENTS The laser diode in the optical pick-up block may suffer electro- static break-down because of the potential difference generated by the charged electrostatic load, etc. on clothing and the human body. During repair, pay attention to electrostatic break-down and also use the procedure in the printed matter which is included in the repair parts. The flexible board is easily damaged and should be handled with care. NOTES ON LASER DIODE EMISSION CHECK The laser beam on this model is concentrated so as to be focused on the disc reflective surface by the objective lens in the optical pick-up block. Therefore, when checking the laser diode emis- sion, observe from more than 30 cm away from the objective lens. Notes on chip component replacement • Never reuse a disconnected chip component. • Notice that the minus side of a tantalum capacitor may be dam- aged by heat. Flexible Circuit Board Repairing • Keep the temperature of the soldering iron around 270 ˚C dur- ing repairing. • Do not touch the soldering iron on the same conductor of the circuit board (within 3 times). • Be careful not to apply force on the conductor when soldering or unsoldering. NOTES ON HANDLING THE OPTICAL PICK-UP BLOCK OR BASE UNIT CAUTION Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous ra- diation exposure. This appliance is classified as a CLASS 1 LASER product. The CLASS 1 LASER PRODUCT MARKING is located on the rear exterior. Laser component in this product is capable of emitting radiation exceeding the limit for Class 1. The following caution label is located inside the unit. CAUTION : INVISIBLE LASER RADIATION WHEN OPEN AND INTERLOCKS DEFEATED. AVOID EXPOSURE TO BEAM. ADVARSEL : USYNLIG LASERSTRÅLING VED ÅBNING NÅR SIKKERHEDSAFBRYDERE ER UDE AF FUNKTION. UNDGÅ UDSAETTELSE FOR STRÅLING. VORSICHT : UNSICHTBARE LASERSTRAHLUNG, WENN ABDECKUNG GEÖFFNET UND SICHEREITSVERRIEGELUNG ÜBERBRÜCKT. NICHT DEM STRAHL AUSSETZEN. VARO! : AVATTAESSA JA SUOJALUKITUS OHITETTAESSA OLET ALT- TIINA NÄKYMÄTTÖMÄLLE LASERSÄTEILYLLE. ÄLÄ KATSO SÄTEESEEN. VARNING : OSYNLING LASERSTRÅLING NÄR DENNA DEL ÄR ÖPPNAD OCH SPÄRREN ÄR URKOPPLAD. BETRAKTA EJ STRÅLEN. ADVERSEL : USYNLIG LASERSTRÅLING NÅR DEKSEL ÅPNES OG SIKKERHEDSLÅS BRYTES. UNNGÅ EKSPONERING FOR STRÅLEN. VIGYAZAT! : A BURKOLAT NYITÁSAKOR LÁTHATATLAN LÉZERSU- GÁRVESZÉLY! KERÜLJE A BESUGÁRZÁST! SECTION 1 SERVICING NOTES www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 4 – MODEL PART No. Thai model 4-214-456-6π Argentine and 120 V AC Area in E models 4-215-169-0π Singapore model 4-215-169-1π Mexican model 4-215-169-2π Saudi Arabia model 4-215-169-3π GRX70J: 240 V AC Area in E model 4-215-169-5π Canadian model 4-219-987-0π GRX70: 240 V AC Area in E model 4-219-987-2π Taiwan model 4-219-987-3π Australian model 4-219-987-4π PART No. MODEL IDENTIFICATION – Rear Panel – www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 5 – HOW TO OPEN THE DISC TRAY WHEN POWER SWITCH TURNS OFF. NOTE FOR INSTALLATION (ROTARY ENCODER) 1 Remove the Case. 3 Pull-out the disc tray. 2 Turn the cam to the direction of arrow. BU cam Groove Section A Note:When attaching the Base unit, Insert the section A into the groove of BU cam. Note:When attaching the BU cam, engage the Rotary encoder switch as shown in the figure. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 6 – SECTION 2 GENERAL This section is extracted from instruction manual. LOCATION OF CONTOROLS – Front Panel – – Rear Panel – 1 CD DIGITAL OUT terminal 2 VIDEO (AUDIO) IN jack 3 FM ANTENNA terminal 4 MD IN/OUT jack 5 SUPER WOOFER jack 6 SURROUND SPEAKER terminal (GRX70/GRX70J) 7 SPEAKER terminal 8 AM ANTENNA terminal 9 VOLTAGE SELECTOR switch (GRX70: 120 V AC Area in E, 240 V AC Area in E, Saudi Arabia, Singapore, Taiwan, Argentine models) @ª EDIT, DIRECTION, TUNER MEMORY button PLAY MODE, DOLBY NR button REPEAT, STEREO/MONO button #º EFFECT button FILE SELECT button GEQ CONTROL button P FILE MEMORY button #¡ FUNCTION button www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 7 – www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 8 – COVER LOADING PANEL ASS’Y Note: Follow the disassembly procedure in the numerical order given. SECTION 3 DISASSEMBLY 3 two screws (case 3TP2) (3 × 8) 2 screw (case 3TP2) (3 × 12) 1 three screws (BVTP3 × 8) 6 cover 2 screw (case 3TP2) (3 × 12) 3 two screws (case 3TP2) (3 × 8) 5 4 4 3 loading panel ass’y 2 Pull-out the disc tray. 1 Turn the cam-in the direction of the arrow A. A www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 9 – FRONT PANEL SECTION CD MECHANISM DECK SECTION (CDM38LH-5BD32L) 2 screw (BVTT3 × 6) 2 screw (BVTT3 × 6) 4 screw (BVTT3 × 10) 6 front panel section 4 screw (BVTP3 × 10) 5 two screws (BVTT3 × 6) 3 lug 3 lug 1 wire (flat type) (15 core) (32 cm) (CN303) 1 wire (flat type) (17 core) (CN304) 1 wire (flat type) (23 core) (CN501) 1 screw (BVTP3 × 10) 2 two screws (BVTP3 × 8) 4 two connectors (CN392, 393) 5 wire (flat type) (19 core) (CN391) 1 screw (BVTP3 × 10) 3 Remove the CD mechanism deck (CDM38LH-5BD32L) in the direction of arrows A – B. B A www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 10 – TAPE MECHANISM DECK SECTION (TCM-230AWR2) MAIN BOARD 1 Push the cassette lid. 4 tape mechanism deck section (TCM-230AWR2) 1 Push the cassette lid. 2 Open two cassette lids. 3 two screws (BVTP2.6 × 8) 3 three screws (BVTP2.6 × 8) 5 five screws (BVTP3 × 8) 5� screw (BVTP3 × 8) (GRX70/GRX70J) 4 two screws (BVTP3 × 8) 7 connector (CN403) 3 two screws (BVTP3 × 8) 2 connector (CN953) (GRX70/GRX70J) 2 connector (CN952) 6 Remove the MAIN board in the direction of the arrow. 1 wire (flat type) 13 core: GRX70: E2, TH, MX, AR, AUS/RXD80 15 core: GRX70: E3, SP, TW/GRX70J (CN371) ( ) • Abbreviation AR : Argentine model AUS : Australian model E2 : 120 V AC Area in E model E3 : 240 V AC Area in E model MX : Mexican model SP : Singapore model TH : Thai model TW : Taiwan model www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 11 – SECTION 4 TEST MODE [MC Cold Reset] • The cold reset clears all data including preset data stored in the RAM to initial conditions. Execute this mode when returning the set to the customer. Procedure: 1. Turn the power ON or set to the DEMO mode. 2. Press three buttons of p , [ENTER/NEXT], and 1/u simulta- neously. 3. The set is reset, and displays “COLD RESET”, then becomes DEMO mode. [MC Hot Reset] • This mode resets the set with the preset data kept stored in the memory. The hot reset mode functions same as if the power cord is plugged in and out. Procedure: 1. Turn the power ON or set to the DEMO mode. 2. Press three buttons of p , [ENTER/NEXT], and [DISC 1] si- multaneously. 3. The set is reset, and becomes standby state. [Change-over the AM Tuning Interval] (EXCEPT Saudi Arabia model) • The AM tuning interval can be changed over 9 kHz or 10 kHz. Procedure: 1. Press the 1/u button to turn the power ON. 2. Select the function “TUNER”, and press the [TUNER/BAND] button to select the BAND “AM”. 3. Press the 1/u button to turn the power OFF. 4. Press the [ENTER/NEXT] and 1/u buttons simultaneously, and the display on the fluorescent indicator tube changes to “AM 9 k STEP” or “AM 10 k STEP”, and thus the tuning interval is changed over. [CD Delivery Mode] • This mode moves the optical pick-up to the position durable to vibration. Use this mode when returning the set to the customer after repair. Procedure: 1. Press the 1/u button to turn the power ON. 2. Press the [LOOP] and 1/u buttons simultaneously. 3. A message “LOCK” is displayed on the fluorescent indicator tube, and the CD delivery mode is set. [LED and Fluorescent Indicator Tube All Lit, Key Check Mode] Procedure: 1. Press three buttons of p , [ENTER/NEXT], and [DISC 2] si- multaneously. 2. LEDs and fluorescent indicator tube are all turned on. Press the [DISC 2] button, and the key check mode is acti- vated. 3. In the key check mode, the fluorescent indicator tube displays “K 0 J0 V0”. Each time a button is pressed, “K” value in- creases. However, once a button is pressed, it is no longer taken into account. “J” value increases like 1, 2, 3 ... if turn the JOG dial clock- wise, or it decreases like 0, 9, 8 ... if turn the JOG dial counter- clockwise. “V” value increases like 1, 2, 3 ... if turn the [VOLUME] dial clockwise, or it decreases like 0, 9, 8 ... if turn the JOG dial counterclockwise. 4. To exit from this mode, press three buttons in the same man- ner as step 1, or disconnect the power cord. [CD Service Mode] • This mode can run the CD sled motor optionally. Use this mode, for instance, when cleaning the optical pick-up. Procedure: 1. Press the 1/u button to turn the power ON. 2. Select the function “CD”. 3. Press three buttons of p , [ENTER/NEXT], and § simulta- neously. 4. Set to the Sled Servo mode. 5. With the CD in stop status, turn the JOG dial clockwise to move the optical pick-up to outside track, or turn it counter- clockwise to inside track. 6. To exit from this mode, perform as follows. 1) Move the optical pick-up to the most inside track. 2) Disconnect the power cord. Notes: • Always move the optical pick-up to most inside track when exiting from this mode. Otherwise, a disc will not be unloaded. • Do not run the sled motor excessively, otherwise the gear can be chipped. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 12 – [Aging Mode] This mode can be used for operation check of CD section and tape deck section. CD section and tape deck section work in parallel. • If an error occurred: The aging operation stops only an error occurred sections and display then status. • If no error occurs: The aging operation continues repeatedly. Procedure: 1. Set disc in DISC1 tray. 2. Load the tapes into the decks A and B respectively. 3. Press the [PLAY MODE] button to set the “ALL DISCS” mode, and press the [REPEAT] button to “REPEAT” off. 4. Press the [FUNCTION] button to select the function “CD”. 5. Press three buttons of p , [ENTER/NEXT], and [DISC SKIP/ EX-CHANGE] simultaneously. 6. The aging mode is activated, if the indicator of disc tray num- ber on the fluorescent indicator tube is blinking. 7. To exit from the aging mode, press the 1/u button to turn the power OFF and operate the cold reset. (Refer to the “MC Cold Reset”) 1. Display at the Aging Mode • Display operating state of CD section and tape deck section al- ternately. • If an error occurred, stop display which that section. 2. CD Section • Display at the aging mode is the same as the normal operation. • The sequence during the aging mode is following as below. Aging mode sequence (CD section) : Turn the disc tray Disc1 chucking TOC read Play track1 for 2 seconds Play last track for 2 seconds • Display at an error occurred 1) Display of the error count (1) Press three buttons of p , [ENTER/NEXT], and [CD SYNC] simultaneously. (2) Display of the error count following as below. Display EMC**EDC** Notes: EMC**: The number of mechanical error. EDC** : The number of no disc error after chucking the disc. 2) Display of mechanical error Display E**M##$$&& Notes: **: The number of mechanical error.(“00” is latest one) (Press the [PLAY MODE] button to changes next error display) ## : Not used. $$ : Loading error. (Second figure is not used) D: The error in the midst of close at the except mechanical trouble. E : The error in the midst of open at the except mechanical trouble. C : The error in the midst of chuck up at the except mechanical trouble. F : The error in the midst of EX-open at the except mechanical trouble. &&: Loading error. (Second figure in not used) 1:The error in the midst of chuck up. 2:The error in the midst of chuck down. 3:Time up of EX-open 4:Time up of EX-close. 3) Display of no disc error Display E**D##$$&& Notes: **: The number of mechanical error.(“00” is latest one) (Press the [REPEAT] button to changes next error display) ##: 01:Focus error 02:GFS error 03:Set up error $$: 00:No disc error when does not chucking retry. 02:No disc error when chucking retry to completion. &&: The state when judged no disc error. (Second figure is not used) 1:Stop 2:Set up 3:TOC read 4:Access 5:Play 6:Pause 7:Manual search (Play) 8:Manual search (Pause) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 13 – 3. Tape Deck Section • The sequence during the aging mode is following as below. • If an error occurred, stop display that step. Aging mode sequence (Tape deck section) : Rewind the tape A and B “TAPE A AG-1” Shut off FWD play the tape A “TAPE A AG-2” 2 minutes Fast forward the tape A “TAPE A AG-3” Shut off or 20 seconds REV play the tape A “TAPE A AG-4” 2 minutes Rewind the tape A “TAPE A AG-5” Shut off FWD play the tape B “TAPE B AG-2” 2 minutes Fast forward the tape B “TAPE B AG-3” Shut off or 20 seconds REV play the tape B “TAPE A AG-4” 2 minutes Rewind the tape B “TAPE B AG-5” Shut off Note: “TAPE * AG-*” is display of each step. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 14 – 1. Demagnetize the record/playback head with a head demagne- tizer. 2. Do not use a magnetized screwdriver for the adjustments. 3. After the adjustments, apply suitable locking compound to the parts adjust. 4. The adjustments should be performed with the rated power supply voltage unless otherwise noted. 5. The adjustments should be performed in the order given in this service manual. (As a general rule, playback circuit ad- justment should be completed before performing recording circuit adjustment.) 6. The adjustments should be performed for both L-CH and R- CH. 7. Switches and controls should be set as follows unless other- wise specified. 8. Set to the DOLBY NR OFF. 9. Set to the test mode. (1) Press the 1/u button to turn the power ON. (2) Select the function “TAPE A or B”. (3) Press the button of p , [ENTER/NEXT], and [DISC 3] simultaneously, to set the tape deck test mode and blink the indicator of disc tray number on the fluorescent indi- cator tube. (4) To exit from the test mode, press the 1/u button. • Test Tape Record/Playback Head Azimuth Adjustment Note: Perform this adjustments for both decks Procedure: 1. Mode: Playback Tape Signal Used for P-4-A100 10 kHz, –10 dB Azimuth Adjustment WS-48B 3 kHz, 0 dB Tape Speed Adjustment P-4-L300 315 Hz, 0 dB Level Adjustment 31 to 71 g • cm (0.43 – 0.98 oz • inch) 2 to 6 g • cm (0.03 – 0.08 oz • inch) 31 to 71 g • cm (0.43 – 0.98 oz • inch) 2 to 6 g • cm (0.03 – 0.08 oz • inch) 71 to 143 g • cm (0.99 – 1.99 oz • inch) 100 g or more (3.53 oz or more) 100 g or more (3.53 oz or more) SECTION 6 ELECTRICAL ADJUSTMENTS SECTION 5 MECHANICAL ADJUSTMENTS Precaution 1. Clean the following parts with a denatured alcohol-moistened swab: record/playback heads pinch rollers erase head rubber belts capstan idlers 2. Demagnetize the record/playback head with a head demagne- tizer. 3. Do not use a magnetized screwdriver for the adjustments. 4. After the adjustments, apply suitable locking compound to the parts adjusted. 5. The adjustments should be performed with the rated power sup- ply voltage unless otherwise noted. Torque Measurement Mode FWD Torque meter CQ-102C Meter reading FWD back tension REV REV back tension FF/REW FWD tension REV tension CQ-102C CQ-102RC CQ-102RC CQ-201B CQ-403A CQ-403R 0 dB=0.775 V DECK SECTION DECK A DECK B set main board MD OUT jack (J101) L-CH, R-CH + – level meter test tape P-4-A100 (10 kHz, –10 dB) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 15 – Screw position L-CH peak within 1dB Output level L-CH peak R-CH peak within 1dB Screw position R-CH peak MAIN board CN301 set test tape P-4-A100 (10 kHz, –10 dB) R-CH oscilloscope L-CH R-CH V H waveform of oscilloscope in phase 45° 90° 135° 180° good wrong main board MD OUT jack (J101) L-CH 2. Turn the adjustment screw and check output peaks. If the peaks do not match for L-CH and R-CH, turn the adjustment screw so that outputs match within 1dB of peak. 3. Mode: Playback 4. Repeat step 1 to 3 in playback (REV) mode. 5. After the adjustments, apply suitable locking compound to the pats adjusted. Adjustment Location: Playback Head (Deck A). Record/Playback/Erase Head (Deck B). Tape Speed Adjustment DECK B Mode: Playback 1. Insert the WS-48B into the deck B. 2. Press the ( button on the deck B. 3. Press the [HI-DUB] button in playback mode. Then at HIGH speed mode. 4. Adjust RV1001 on the LEAF SW board do that frequency counter reads 6,000 ± 180 Hz. 5. Press the [HI-DUB] button. Then back to NORMAL speed mode. 6. Adjust RV1002 on the LEAF SW board so that frequency counter reads 3,000 ± 90 Hz. Adjustment Location: LEAF SW board Sample value of Wow and Flutter: 0.3% or less W.RMS (JIS) (WS-48B) Playback level Adjustment DECK A DECK B Procedure: Mode: Playback Deck A is RV311 (L-CH) and RV411 (R-CH), Deck B is RV301 (L-CH) and RV401 (R-CH) so that adjustment within adjustment level as follows. Adjustment Level: J101 PB level: 301.5 to 338.3 mV (–8.2 to –7.2 dB) level difference between the channels: within ±0.5 dB Adjustment Location: AUDIO board forward reverse + – set test tape WS-48B (3 kHz, 0 dB) main board MD OUT jack (J101) L-CH, R-CH frequency counter + – set test tape P-4-L300 (315 Hz, 0 dB) main board MD OUT jack (J101) L-CH, R-CH level meter www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 16 – REC Bias Adjustment DECK B Procedure: 1. Mode: Record FUNCTION: VIDEO 2. Mode: Playback 3. Confirm playback the signal recorded in step 1 become speci- fication values as follows. If these values are out of specification values, adjust the RV341 (L-CH) and RV441 (R-CH) on the AUDIO board to repeat steps 1and 2. Specification values: Playback output of 315 Hz to playback output of 10 kHz: ± 0.5 dB Adjustment Location: AUDIO board REC Level Adjustment DECK B Procedure: 1. Mode: Record FUNCTION: VIDEO 2. Mode: Playback 3. Confirm playback the signal recorded in step 1 become speci- fication values as follows. If these values are out of specification values, adjust the RV301 (L-CH) and RV351 (R-CH) on the MAIN board to repeat steps 1 and 2. Specification values: J101 PB level: 47.2 to 53.0 mV (–24.3 to –23.3 dB) Adjustment Location: MAIN board – MAIN BOARD (Conductor Side) – – AUDIO BOARD (Component Side) – – LEAF SW BOARD (Component Side) – attenuator set main board VIDEO (AUDIO) IN jack (J101) L-CH, R-CH 1) 315 Hz 2) 10 kHz 50 mV (–23.8 dB)    600 Ω blank tape CN-123 AF OSC + – set recorded portion main board MD OUT jack (J101) L-CH, R-CH level meter set main board VIDEO (AUDIO) IN jack (J101) L-CH, R-CH 315 Hz, 50 mV (–23.8 dB) blank tape CS-123 600 Ω attenuator AF OSC + – set recorded portion main board MD OUT jack (J101) L-CH, R-CH level meter RV301 L RV351 R IC301 REC LEVEL J101 VIDEO (AUDIO) IN (L/R) MD OUT (L/R) RV401 RV301 RV341 RV311 RV411 IC602 CN601 L R R L       RV441 PB LEVEL – DECK B – REC BIAS L R    PB LEVEL – DECK A – TAPE SPEED RV1002 RV1001 (NORMAL) (HIGH) CN1001           www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 17 – Note: 1. CD Block is basically designed to operate without adjustment. There- fore, check each item in order given. 2. Use YEDS-18 disc (3-702-101-01) unless otherwise indicated. 3. Use an oscilloscope with more than 10 MΩ impedance. 4. Clean the object lens by an applicator with neutral detergent when the signal level is low than specified value with the following checks. S-Curve Check Procedure: 1. Connect oscilloscope to TP (FE). 2. Connect between TP (FE1) and TP (VC) by lead wire. 3. Connect between TP (AGCCON) and TP (GND) by lead wire. 4. Turn the power ON. 5. Load a disc (YEDS-18) and actuate the focus search. (In con- sequence of open and close the disc tray, actuate the focus search) 6. Cofirm that the oscilloscope waveform (S-curve) is symmetri- cal between A and B. And confirm peak to peak level within 4 ± 1 Vp-p. S-curve waveform 7. After check, remove the lead wire connected in step 2 and 3. Note: • Try to measure several times to make sure than the ratio of A : B or B : A is more than 10 : 7. • Take sweep time as long as possible and light up the brightness to obtain best waveform. RF Level Check Procedure: 1. Connect oscilloscope to TP (RF). 2. Connect between TP (AGCCON) and TP (GND) by lead wire. 3. Turn the power ON. 4. Load a disc (YEDS-18) and playback. 5. Confirm that the oscilloscope waveform is clear and check RF signal level is correct or not. 6. After check, remove the lead wire connected in step 2. Note: Clear RF signal waveform means that the shape “≈” can be clearly distinguished at the center of the waveform. CD SECTION + – BD board TP (FE) TP (VC) oscilloscope A B symmetry within 4 ± 1 Vp-p + – BD board TP (TE) TP (VC) oscilloscope VOLT/DIV: 200 mV TIME/DIV: 500 ns level: 1.45 ± 0.3 Vp-p E-F Balance (1 Track Jump) Check Procedure : 1. Connect oscilloscpe to TP (TE) and TP (VC). 2. Turn the power ON. 3. Load a disc (YEDS-18) and playback the number five track. 4. Press the ^ (CD) button. (Becomes the 1 track jump mode) 5. Confirm that the level B and A (DC voltage) on the oscillo- scope waveform. 1 track jump waveform Specified level: × 100 = less than ± 22% 6. After check, remove the lead wire connected in step 1. A B + – BD board TP (TE) TP (VC) oscilloscope A (DC voltage) center of waveform B 0V level = 1.3 ± 0.6 Vp-p symmetry www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 18 – Checking Location: – BD BOARD (Side B) – TP (VC) TP (FE) TP (FE1) TP (TE) TP (RF) TP (AGCCON) TP (GND) IC102 IC103 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com HCD-GRX70/GRX70J/RXD80 – 19 – – 20 – SECTION 7 DIAGRAMS 7-1. BLOCK DIAGRAM – CD SERVO Section – SQSO SQCK A/D CONVERTER CH1OUTF CH1OUTR 5 4 7 2 1 5 10 6 6 7 8 16 14 13 10 11 22 4 3 51 49 48 43 24 41 40 39 64 15 28 29 30 31 32 33 24 25 23 5 6 2 3 17 18 15 16 E B C D A CD D+5V F DETECTOR A B C D RF SUMMING AMP FOCUS ERROR AMP RF EQ AMP TRACKING ERROR AMP RFO FE RF AMP, FOCUS/TRACKING ERROR AMP IC103 TE E F F I-V AMP E I-V AMP AUTOMATIC POWER CONTROL Q101 APC LD AMP APC PD AMP LD LD PD LASER DIODE RFAC ASYO ASYI ASYMMETRY CORRECTION DIGITAL PLL DIGITAL SIGNAL PROCESSOR, DIGITAL FILTER, D/A CONVERTER IC101 (1/2) DATA XLAT CLOK 14 5 6 MDP 26 7 8 XLON 3 XRST DIGITAL CLV D/A INTERFACE SE TE FE RFDC FOCUS/TRACKING/SLED SERVO DSP FOCUS/TRACKING/SLED PWM GENERATOR SFDR CH3FIN CH4SIN CH3RIN CH3OUTF CH3OUTR CH2FIN CH2RIN CH1FIN CH1RIN 20 MUTE SRDR TFDR TRDR FFDR FRDR S101 (LIMIT) EMPH WFCK GFS MIRR/DFCT/ FOK DETECTOR SERVO AUTO SEQUENCER SERVO INTERFACE CPU INTERFACE 18 63 62 61 19 SENS 20 35 57 58 37 56 19 SCOR SQ-DATA SQ-CLK CD-DATA XLT CD-CLK SENSE SCOR 1 2 32 33 SCLK COUT 9 21 SSTP 27 FOK 22 23 MIRR DFCT TO SERVO INTERFACE CH4OUTF CH4OUTR M101 (SPINDLE) MOTOR DRIVE MOTOR DRIVE COIL DRIVE CH2OUTF CH2OUTR COIL DRIVE M M M102 (SLED) 05 FOCUS/TRACKING COIL DRIVE, SPINDLE/SLED MOTOR DRIVE IC102 2-AXIS DEVICE (TRACKING) (FOCUS) DIGITAL SERVO PROCESSOR IC101 (2/2) OPTICAL PICK-UP (KSS-213D/Q-NP) LDON 21 HOLD SW PD I-V AMP 12 11 13 14 54 56 53 55 FILTER FILO PCO CLTV FILI EFM DEMODULATOR SERIAL IN INTERFACE DIGITAL FILTER, NOISE SHAPER PWM & INTEGRATOR BUFFER CLOCK GENERATOR OPTICAL TRANSCEIVER IC381 IC381 CD DIGITALOUT OPTICAL TIMING LOGIC DIGITAL OUT INTERNAL BUS 16K RAM ERROR CORRECTOR SUBCODE PROCESSOR 60 HOLD 59 XRST XTAI X101 16.9344MHz AIN1 AIN2 R-CH CD-L AOUT1 AOUT2 TO MIRR/DFCT/ FOK DETECTOR PCMD BCK LRCK C2PO DOUT 66 XTAO 67 70 77 LOUT1 LOUT2 72 75 71 76 • SIGNAL PATH : CD PLAY (ANALOG OUT) : CD PLAY (DIGITAL OUT) SYSTEM CONTROLLER (CD MECHANISM CONTROL) IC501 (1/4) When the optical pick-up is inner position. ON : DISC TRAY ADDRESS DETECT (Page 23) A TBL-L TBL-R M 3 6 7 2 MOTOR DRIVE DISC TRAY TURN MOTOR DRIVE IC701 OUT1 OUT2 IN1 IN2 M701 (DISC TRAY TURN) LEVEL SHIFT Q701 DISC IN DETECT SENSOR IC703 DISC TRAY SENSOR IC702 ROTARY ENCODER S811 DISC-SENS OUT-OPEN S801 (OPEN/CLOSE DET) ENC1 ENC2 ENC3 60 TBL-SENS 61 4 70 CLOSE OPEN 71 69 68 2 3 63 65 LOAD-OUT LOAD-IN M 10 2 7 4 MOTOR DRIVE DISC TRAY SLIDE MOTOR DRIVE IC801 OUT1 OUT2 FIN RIN M801 (DISC TRAY SLIDE) 66 67 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com HCD-GRX70/GRX70J/RXD80 – 21 – – 22 – 7-2. BLOCK DIAGRAM – TAPE DECK Section – PB EQ AMP (DECK A) IC611 PB LEVEL (L) (DECK A) REC-L PB-L CAPSTAN MOTOR CONTROL SWITCH Q1001 CAPSTAN MOTOR DRIVE Q336 – 343 1 B (Page 23) (Page 24) L-CH R-CH R-CH HP101 (PLAYBACK) PB EQ AMP (DECK B) IC601 L-CH R-CH R-CH 05 R-CH R-CH HRPE101 (1/2) (RECORD/PLAYBACK) ALC REC EQ AMP AMS CIRCUIT DOLBY NR AMP CIRCUIT BIAS CONTROL CIRCUIT DOLBY PASS R-CH L.P.F. BUFFER Q335 M M1 (CAPSTAN) HRPE101 (2/2) (ERASE) BIAS OSC T621 B+ (A+7V) R-CH 3 46 28 43 36 40 35 34 39 26 77 19 15 16 18 20 22 23 24 25 17 85 84 83 82 81 80 79 78 31 33 32 + 48 4 2 RV311 PB LEVEL (L) (DECK B) RV301 TAPE SPEED (NORMAL) RV1002 TAPE SPEED (HIGH) RV1001 REC LEVEL (L) (DECK B) RV301 REC BIAS (R) (DECK B) RV441 REC BIAS (L) (DECK B) BIAS OSC Q621, 622 REC BIAS SWITCH Q623 ROTATION DETECT SENSOR (DECK A) IC1001 RV341 BIAS TRAP C331, L331 REC/PB SWITCHING IC602 SYSTEM CONTROLLER IC501 (2/4) DECK PROCESS DECK A/B SELECT, PB/REC EQ AMP, DOLBY NR AMP, ALC, AMS IC301 AIN (L) BIN (L) MAOUT PB OUT (L) EQ OUT (L) MSIN MSOUT BIAS ON/OFF 70 120 BIAS (N) BIAS (C) BIAS (M) S1004 A 120/70 B NORM/CROM ALC ON/OFF PB A/B NORM/HIGH NR ON/OFF RM ON/OFF REC/PB/PASS LM ON/OFF (DECK A 120/70) 88 S1003 (DECK A HALF) S1001 (DECK A PLAY) S1002 (DECK B PLAY) S1008 (DECK B 120/70) 27 REC OUT (L) ROUT (L) RIN (L) ALC (L) EQ IN (L) ALC IN (L) 44 38 100 AMS-IN 91 A-SHUT ROTATION DETECT SENSOR (DECK B) IC1002 90 B-SHUT TRIGGER PLUNGER DRIVE (DECK A) Q333, 334 73 A-TRG TC-MUTE R/P-PASS NR-ON/OFF REC-MUTE BIAS EQ-H/N PB-A/B ALC-ON/OFF TC-RELAY A-PLAY-SW B-PLAY-SW A-HALF 89 S1006 (DECK B HALF) S1009 (DECK B REC) S1005 (DECK A REC) B-HALF TRIGGER PLUNGER DECK A TRIGGER PLUNGER DRIVE (DECK B) Q331, 332 72 B-TRG 76 74 75 CAP-M-H/L CAPM-CNT2 CAPM-CNT1 TRIGGER PLUNGER DECK B 87 86 C • SIGNAL PATH : PLAYBACK (DECK A) : PLAYBACK (DECK B) : RECORD D+5V w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com HCD-GRX70/GRX70J/RXD80 – 23 – – 24 – 7-3. BLOCK DIAGRAM – MAIN Section – DBFB CONTROL SWITCH Q111 BASS FREQUENCY CONTROL SWITCH Q201 RESET SIGNAL GENERATOR IC502 POWER AMP IC801 CD-L J101 (1/2) A (Page 20) (Page 22) C (Page 22) PB-L B (Page 25) SPEANA D R-CH R-CH R-CH 05 FM/AM TUNER UNIT VOLUME CONTROL CPU INTERFACE BASS BOOST CONTROL CIRCUIT INPUT SELECT SWITCH SOUND CONTROL CIRCUIT GRAPHIC EQUALIZER CONTROL CIRCUIT R-CH FEED BACK SWITCH Q112 R-CH COMMAND F OUT2 BUF OUT2 VOL IN2 + + R-CH R-CH R-CH R-CH D141 R-CH + + + MIC LEVEL RV712 ECHO LEVEL RV711 MIC AMP IC712 (2/2) MUTING Q113 OVER LOAD DETECT Q801 TEMPERATURE DETECT SWITCH Q831, 832 DC DETECT SWITCH Q433, 434 RESET SWITCH Q501 RELAY DRIVE Q431 INPUT SELECT SWITCH, GRAPHIC EQUALIZER CONTROL, ELECTRICAL VOLUME IC101 IN E2 IN D2 IN B2 IN A2 IN C2 KEY IN2 KEY IN1 KEY OUT 2 KEY OUT 1 L+R DATA CLOCK LATCH 493-DATA 493-CLK 493-LATCH DBFB-H/L BASS FREQ. PROTECTOR XC-OUT X613 16MHz X601 32.768kHz XC-IN X-OUT X-IN BB B2, BB A2 MIC IN SUPER WOOFER REC A2 REC-L D191 REC B2 • SIGNAL PATH : CD PLAY : TAPE PLAY : RECORD : TUNER (FM/AM) : MIC INPUT TH831 +5V R-CH + R-CH R-CH M501 (FAN) R-CH –1 –2 + MUTING Q191 MUTING Q411, 471 FAN MOTOR DRIVE Q401, 402 PROTECT SWITCH Q192 R-CH R-CH OVER LOAD DETECT SWITCH Q432 PROTECT SWITCH Q439 PROTECT SWITCH Q435, 436 OVER LOAD DETECT SWITCH Q437 STANDBY SWITCH Q803, 804, 881 MUTING CONTROL SWITCH Q508, 509 MUTING CONTROL SWITCH Q412 J701 PHONES TM401 SPEAKER IMPEDANCE USE 6 – 16Ω TM402 SURROUND SPEAKER IMPEDANCE USE 16Ω J711 MIX MIC L L R R VIDEO (AUDIO) IN MD IN J101 (2/2) L R MD OUT J191 SUPER WOOFER ANTENNA ST-L FM ANT FM ANT AM ANT AM ANT ST-R ST-MUTE STEREO TUNED ST-DIN ST-DOUT ST-CLK ST-CE ST-MUTE STEREO TUNED ST-DOUT ST-DIN ST-CLK ST-CE FM 75Ω AM 38, 39 D607 D644 D803 RY401 + – – + L R + – – + SYSTEM CONTROLLER IC501 (3/4) + MIC AMP IC712 (1/2) DIGITAL ECHO IC711 (Page 25) RESET E (GRX70J: Saudi Arabia) 27 F-RELAY 3 11 10 13 15 7 44 STK-MUTE 1 LINE-MUTE RESET 6 12 AC-CUT 22 RY-SW 36 47 48 38 60 5 59 6 30 2 58 57 42 41 72 36 34 BUF IN2 37 32 33 49 50 51 54 53 52 55 65 66 68 69 67 M L R w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com HCD-GRX70/GRX70J/RXD80 7-4. BLOCK DIAGRAM – DISPLAY/KEY CONTROL/POWER SUPPLY Section – – 25 – – 26 – REGULATOR CONTROL SWITCH Q903, 923 D925 D501, 502 +7V REGULATOR IC901 –26V (FL DRIVER (IC601) B–) +12V REGULATOR IC903 +10V REGULATOR Q909 –7V REGULATOR Q914, 951, 952 +7V REGULATOR Q901, 902, 913 ST +10V (FM/AM TUNER UNIT B+) TC M+12V (TC MOTOR SECTION B+) CD M+7V (CD MOTOR SECTION B+) B+ SWITCH Q907, 908 D509 B+ SWITCH Q904, 905 +5V REGULATOR IC902 +5V REGULATOR IC11 RECT D907 – 910 RECT D901 – 904 RECT D12 – 15 AC IN POWER AMP (IC801), PROTECTOR CIRCUIT POWER TRANSFORMER T951 RECT D17 – 20 RECT D832 RECT D831 VOLTAGE SELECTOR S951 RECT D971 RELAY DRIVE Q11 FL ON/OFF SWITCH Q12, 17 FL ON/OFF SWITCH Q14 – 16 –26V REGULATOR Q13 –26V REGULATOR Q971 AC IN SUB POWER TRANSFORMER T11 RY11 +7V TC, PANEL, AUDIO –7V FAN MOTOR B– VF1 TO FLUORESCENT INDICATOR TUBE (FL601) VF2 B+ B– B+ B– REMOTE CONTROL RECEIVER IC602 GRID DRIVE Q607 – 612 FLUORESCENT INDICATOR TUBE DRIVER, KEY CONTROL IC601 SYSTEM CONTROLLER IC501 (4/4) LED DRIVER IC604 BAND-PASS FILTER IC603 Q603 LED +5V S LOW FREQ (BPF0) 18 BPF2 19 BPF3 20 BPF4 GRID DRIVE Q613 DET DET B.P.F. 21 ALL BAND (L+R) REC IN LINE IN 1 SIRCS ROTARY ENCODER S601 ROTARY ENCODER S602 2 JOG-A 9 VOL-A 8 JOG-B 10 72 70 VOL-B XOUT XIN B+ SWITCH Q601, 602 LED DRIVE Q606 KEY0 – KEY3 BPF1 F01 F04 F05 F06 F02 GR1 (Page 23) (Page 23) D D611 – 616, 619 – 622, 624, D627 – 631, 751 – 753 SPEANA L SEL 7 TIMER LED 26 LED DATA 5 LED SCK 3 LED LAT DATA CLK 4 13 14 15 45 I2C DATA I2C CLK IIC-DATA FL SW IIC-CLK RESET RESET 17 79 78 29 WAKE UP WAKE UP 22 18 30 42 STBY RELAY 43 CD-POWER 5 POWER 2 73 16 14 13 12 L+R 11 16 17 4 6 11 – 14 S1 – S22 46 – 67 G13 – G18 32 – 27 G2 – G12 44 – 42, 40 – 33 17, 19 – 23, 2, 3, 5, 7, 10, 11 P1 – P6, P8, P9, P11, P12, P15, P16 S601 (JOG DIAL) S611 – 630, S638 – 651, 751 – 757 05 S602 VOLUME X601 12.5MHz E STB LED DRIVE Q604, 605 STBY LED 39 D632 TIMER SELECT D754 I/u (RXD80) (GRX70/GRX70J) (GRX70/GRX70J) (GRX70/GRX70J) (GRX70/GRX70J) (RXD80) (RXD80) (RXD80) (RXD80) GRX70: Thai, Mexican, Australian/RXD80 GRX70: E2, E3, Singapore, Hong Kong, Taiwan, Argentine/GRX70J GRX70/ GRX70J CD D+5V, CD A+5V CD MECHANISM DECK SECTION B+ +5V SYSTEM CONTROLLER (IC501) B+ D+5V M62493FP (IC101), CD SENSOR CIRCUIT B+ D923 D405 – 407 (GRX70/GRX70J) (RXD80) D+5V (TAPE DECK SECTION B+) +5V (STBY) (PANEL SECTION B+) LED +5V (PANEL SECTION B+) D922 (GRX70/GRX70J) (RXD80) D924 (GRX70/GRX70J) (RXD80) FLUORESCENT INDICATOR TUBE FL601 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 27 – – 28 – 7-5. NOTE FOR PRINTED WIRING BOARDS AND SCHEMATIC DIAGRAMS Note on Printed Wiring Board: • X : parts extracted from the component side. • Y : parts extracted from the conductor side. • p : parts mounted on the conductor side. • ¢ : internal component. • b : Pattern from the side which enables seeing. (The other layers' patterns are not indicated.) • Indication of transisitor. Caution: Pattern face side: Parts on the pattern face side seen from (Side B) the pattern face are indicated. Parts face side: Parts on the parts face side seen from (Side A) the parts face are indicated. Note on Schematic Diagram: • All capacitors are in µF unless otherwise noted. pF: µµF 50 WV or less are not indicated except for electrolytics and tantalums. • All resistors are in Ω and 1/4 W or less unless otherwise specified. • ¢ : internal component. • 2 : nonflammable resistor. • 5 : fusible resistor. • C : panel designation. • U : B+ Line. • V : B– Line. • H : adjustment for repair. • Voltages are taken with a VOM (Input impedance 10 MΩ). Voltage variations may be noted due to normal produc- tion tolerances. • Waveforms are taken with a oscilloscope. Voltage variations may be noted due to normal produc- tion tolerances. • Circled numbers refer to waveforms. • Signal path. F : TUNER (FM/AM) E : PLAYBACK (DECK A) d : PLAYBACK (DECK B) G : RECORD J : CD PLAY (ANALOG OUT) c : CD PLAY (DIGITAL OUT) N : MIC INPUT • Abbreviation AR : Argentine model AUS : Australian model CND : Canadian model E2 : 120 V AC Area in E model E3 : 240 V AC Area in E model EA3 : Saudi Arabia model MX : Mexican model SP : Singapore model TH : Thai model TW : Taiwan model Note: The components identi- fied by mark ! or dotted line with mark ! are criti- cal for safety. Replace only with part number specified. Note: Les composants identifiés par une marque ! sont critiques pour la sécurité. Ne les remplacer que par une piéce portant le numéro spécifié. B These are omitted. C E Q B These are omitted. C E Q • Circuit Boards Location CD SW board SUB TRANS board (RXD80) TRANS board MAIN board PANEL board TUNER PACK (GRX70: MX, AR/RXD80) TUNER (FM/AM) (GRX70: E2, TH, AUS) TUNER (FM/MW/SW) (GRX70: E3, SP, TW/GRX70J) CONNECTOR board SENSOR board MOTOR (TURN) board MOTOR (SLIDE) board LEAF SW board AUDIO board BD board • Abbreviation AR : Argentine model AUS : Australian model E2 : 120 V AC Area in E model E3 : 240 V AC Area in E model MX : Mexican model SP : Singapore model TH : Thai model TW : Taiwan model w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com HCD-GRX70/GRX70J/RXD80 – 29 – – 30 – 7-6. PRINTED WIRING BOARD – BD Board – • See page 28 for Circuit Boards Location. • Semiconductor Location (Side A) Ref. No. Location Q101 C-3 • Semiconductor Location (Side B) Ref. No. Location IC101 C-2 IC102 B-1 IC103 B-1 (Page 43) 05 05 KSS-213D/Q-NP 19 ) ( ) ( ) ( TP(VC) TP(RF) TP(TE) TP(FE1) TP(FE) TP (AGCCON) TP(GND) 21 21 31 31 , , 21 21 31 31 , , w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com HCD-GRX70/GRX70J/RXD80 – 31 – – 32 – 7-7. SCHEMATIC DIAGRAM – BD Board – • See page 59 for Waveforms. • See page 64 for IC Block Diagrams. • Voltages and waveforms are dc with respect to ground under no-signal conditions. no mark : CD STOP ( ) : CD PLAY The components identified by mark ! or dotted line with mark ! are critical for safety. Replace only with part number specified. Les composants identifiés par une marque ! sont critiques pour la sécurité. Ne les remplacer que par une piéce portant le numéro spécifié. (Page 45) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com HCD-GRX70/GRX70J/RXD80 – 33 – – 34 – 7-8. PRINTED WIRING BOARDS – CD MOTOR Section – • See page 28 for IC Circuit Boards Location. 05 B DISC TRAY SLIDE (DISC TRAY ADDRESS DETECT) DISC TRAY TURN 1-658-577- C (Page 43) (Page 43) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com HCD-GRX70/GRX70J/RXD80 – 35 – – 36 – 7-9. SCHEMATIC DIAGRAM – CD MOTOR Section – • See page 65 for IC Block Diagrams. • Voltages are dc with respect to ground under no-signal conditions. no mark : CD STOP (Page 45) (Page 45) DISC TRAY ADDRESS DETECT DISC TRAY SLIDE CLOSE OPEN B (DISC TRAY SLIDE) DISC IN DETECT SENSOR DISC TRAY SENSOR DISC TRAY TURN DISC TRAY TURN MOTOR DRIVER LEVEL SHIFT C w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com HCD-GRX70/GRX70J/RXD80 – 37 – – 38 – 7-10. PRINTED WIRING BOARD – AUDIO Board – • See page 28 for Circuit Boards Location. (Page 43) 05 D ( ) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com HCD-GRX70/GRX70J/RXD80 PB LEVEL (L) (DECK A) PB LEVEL (R) (DECK A) PB LEVEL (L) (DECK B) PB LEVEL (R) (DECK B) PB EQ AMP (DECK A) PB EQ AMP (DECK B) SWITCHING REC BIAS (L) (DECK B) REC BIAS (R) (DECK B) BIAS OSC REC BIAS -6.8 (PLAYBACK) D – 39 – – 40 – 7-11. SCHEMATIC DIAGRAM – AUDIO Board – • See page 66 for IC Block Diagram. • Voltages are dc with respect to ground under no-signal conditions. no mark : TAPE PLAY ( ) : RECORD The components identified by mark ! or dotted line with mark ! are critical for safety. Replace only with part number specified. Les composants identifiés par une marque ! sont critiques pour la sécurité. Ne les remplacer que par une piéce portant le numéro spécifié. (Page 49) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com HCD-GRX70/GRX70J/RXD80 DECK B PLUNGER DECK A PLUNGER (CAPSTAN) (DECK A 120/70) (DECK A HALF) (DECK A REC) (DECK B HALF) (DECK B REC) (DECK B 120/70) ROTATION DETECT SENSOR (DECK A) ROTATION DETECT SENSOR (DECK B) (DECK A PLAY) (DECK B PLAY) E CONTROL SWITCH – 41 – – 42 – 7-12. PRINTED WIRING BOARD – LEAF SW Board – • See page 28 for Circuit Boards Location. 7-13. SCHEMATIC DIAGRAM – LEAF SW Board – • Voltages are dc with respect to ground under no-signal conditions. no mark : TAPE PLAY ( ) : RECORD ∗ : Impossible to measure Q113 E-9 Q161 C-9 Q162 C-9 Q163 E-9 Q191 E-12 Q192 E-10 Q201 D-9 Q251 C-9 Q331 C-1 Q332 C-2 Q333 C-2 Q334 C-2 Q335 D-1 Q336 F-1 Q337 F-1 Q338 F-1 Q339 F-1 Q340 E-1 Q341 E-1 Q342 F-1 Q343 E-1 Q401 F-12 Q402 E-12 Q411 G-2 Q412 G-3 Q431 G-12 Q432 G-11 Q433 F-11 Q434 F-11 Q435 F-11 Q436 F-11 Q437 G-12 Q439 F-12 Q471 F-2 Q501 D-7 Q508 D-7 Q509 E-7 Q801 H-10 Q803 G-10 Q804 G-9 Q831 G-10 Q832 G-10 Q851 J-10 Q881 I-9 Q901 H-2 Q902 I-1 Q903 H-1 Q904 G-4 Q905 G-4 Q907 G-5 Q908 G-4 Q909 I-4 Q913 H-1 Q914 G-2 Q923 H-1 Q951 G-2 Q952 H-1 Ref. No. Location Ref. No. Location D141 E-10 D191 E-12 D331 E-1 D333 F-1 D334 E-1 D335 F-1 D401 G-11 D403 F-12 D405 H-6 D406 J-4 D407 I-2 D411 G-3 D501 D-7 D502 E-6 D503 D-6 D504 D-7 D505 D-7 D506 D-7 D509 F-2 D607 E-5 D644 C-8 D801 J-11 D802 G-9 D803 G-11 D831 I-6 D832 J-7 D851 J-10 D852 G-9 D881 H-9 D901 J-4 D902 J-4 D903 J-4 D904 I-4 D905 I-1 D906 H-1 D907 J-5 D908 I-5 D909 J-5 D910 J-5 D915 I-4 D921 H-4 D922 G-4 D923 G-4 D924 F-2 D925 G-4 IC101 C-10 IC301 B-3 IC381 A-12 IC501 D-5 IC502 D-7 IC801 H-10 IC901 G-6 IC902 G-4 IC903 H-4 Q111 D-10 Q112 D-10 • Semiconductor Location (Page 49) (Page 43) 05 DECK A PLUNGER DECK B PLUNGER (DECK A PLAY) (DECK A HALF) (DECK A 120/70) (DECK A REC) (DECK B HALF) (DECK B PLAY) (DECK B 120/70) (DECK B REC) 21 21 E 4 1 2 3 4 1 2 3 ( ) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com HCD-GRX70/GRX70J/RXD80 – 43 – – 44 – 7-14. PRINTED WIRING BOARD – MAIN Board – • See page 28 for Circuit Boards Location. (Page 38) (Page 41) (Page 53) (Page 61) (Page 33) (Page 33) (Page 30) (Page 61) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com HCD-GRX70/GRX70J/RXD80 – 45 – – 46 – 7-15. SCHEMATIC DIAGRAM – MAIN Board (1/4) – • Voltages and waveforms are dc with respect to ground under no-signal (detuned) conditions. no mark : TUNER (FM/AM) ( ) : CD PLAY (Page 31) (Page 36) (Page 36) (Page 50) (Page 51) (Page 47) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com HCD-GRX70/GRX70J/RXD80 – 47 – – 48 – 7-16. SCHEMATIC DIAGRAM – MAIN Board (2/4) – • Voltages are dc with respect to ground under no-signal (detuned) conditions. no mark : FM The components identified by mark ! or dotted line with mark ! are critical for safety. Replace only with part number specified. Les composants identifiés par une marque ! sont critiques pour la sécurité. Ne les remplacer que par une piéce portant le numéro spécifié. (Page 46) (Page 50) (Page 52) (Page 63) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com HCD-GRX70/GRX70J/RXD80 – 49 – – 50 – 7-17. SCHEMATIC DIAGRAM – MAIN Board (3/4) – • Voltages are dc with respect to ground under no-signal (detuned) conditions. no mark : TUNER (FM/AM) ( ) : CD PLAY { } : TAPE PLAYBACK (DECK A) [ ] : TAPE PLAYBACK (DECK B) 〈〈 〉〉 : RECORD (Page 40) (Page 42) (Page 46) (Page 47) (Page 51) (Page 63) (Page 56) (Page 51) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com HCD-GRX70/GRX70J/RXD80 – 51 – – 52 – 7-18. SCHEMATIC DIAGRAM – MAIN Board (4/4) – • See page 59 for Waveforms. • Voltages and waveforms are dc with respect to ground under no-signal (detuned) conditions. no mark : TUNER (FM/AM) ( ) : CD PLAY { } : TAPE PLAYBACK (DECK A) [ ] : TAPE PLAYBACK (DECK B) 〈〈 〉〉 : RECOARD uPC7812AHF (Page 46) (Page 50) (Page 50) (Page 48) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com HCD-GRX70/GRX70J/RXD80 – 53 – – 54 – 7-19. PRINTED WIRING BOARD – PANEL Board – • See page 28 for Circuit Boards Location. D628 E-4 D629 D-5 D630 F-7 D631 F-4 D632 F-8 D701 C-9 IC601 B-5 IC602 B-10 IC603 B-7 IC604 C-3 IC711 C-9 IC712 F-8 Ref. No. Location Ref. No. Location D610 C-2 D611 E-1 D612 C-2 D613 C-5 D614 C-6 D615 C-7 D616 C-8 D619 B-2 D620 A-2 D621 B-9 D622 A-9 D624 D-4 D627 E-7 • Semiconductor Location Ref. No. Location Q601 C-2 Q602 C-1 Q603 C-1 Q604 A-3 Q605 A-2 Q606 B-3 Q607 A-9 Q608 A-9 Q609 A-9 Q610 B-9 Q611 B-8 Q612 B-8 Q613 B-8 (Page 43) (Page 57) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com HCD-GRX70/GRX70J/RXD80 – 55 – – 56 – 7-20. SCHEMATIC DIAGRAM – PANEL Board– • See page 59 for Waveform. • See page 66 for IC Block Diagrams. • Voltages and waveforms are dc with respect to ground under no-signal (detuned) conditions. no mark : TUNER (FM/AM) (Page 58) (Page 50) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com HCD-GRX70/GRX70J/RXD80 – 57 – – 58 – 7-21. PRINTED WIRING BOARD – CD SW Board – • See page 28 for Circuit Boards Location. 7-22. SCHEMATIC DIAGRAM – CD SW Board – (Page 55) (Page 54) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 59 – • Waveforms – BD Board – 1 IC101 ^¶ (XTAO) 5 IC101 @§ (MDP) 2 IC101 %¡ (RF AC) (CD Play Mode) 3 IC101 $¡ (TE) (CD Play Mode) 4 IC101 #ª (FE) (CD Play Mode) 6 IC102 !§ (RFO) (CD Play Mode) 2 IC501 !∞ (XIN) – MAIN Board – 1 IC501 0 (XC-IN) 3.1 Vp-p 16.9344 MHz 1.2 Vp-p 0.2 Vp-p 0.5 Vp-p 2.5 Vp-p 7.8 µs 1.3 Vp-p 1.8 Vp-p 32.768 kHz 2.2 Vp-p 16 MHz – PANEL Board – 1 IC601 &™ (XOUT) 4.7 Vp-p 12.5 MHz w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com HCD-GRX70/GRX70J/RXD80 – 61 – – 62 – • Semiconductor Location Ref. No. Location D971 A-2 D972 A-1 D973 A-1 Q971 A-1 7-23. PRINTED WIRING BOARDS – TRANSFORMER Section – • See page 28 for Circuit Boards Location. • Semiconductor Location Ref. No. Location D11 B-5 D12 A-3 D13 A-3 D14 A-3 D15 A-3 D16 B-2 D17 A-2 D18 A-2 D19 A-2 D20 A-2 D21 A-2 D22 A-2 D23 A-1 IC11 B-2 Q11 B-2 Q12 A-2 Q13 A-2 Q14 A-1 Q15 A-1 Q16 A-1 Q17 A-1 (Page 43) (Page 43) (Page 43) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 63 – HCD-GRX70/GRX70J/RXD80 7-24. SCHEMATIC DIAGRAM – TRANSFORMER Section – • Voltages are dc with respect to ground under no-signal (detuned) conditions. no mark : TUNER (FM/AM) The components identified by mark ! or dotted line with mark ! are critical for safety. Replace only with part number specified. Les composants identifiés par une marque ! sont critiques pour la sécurité. Ne les remplacer que par une piéce portant le numéro spécifié. (Page 48) (Page 50) (Page 50) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 64 – • IC Block Diagrams – BD Board – IC101 CXD2587Q TE RFDC CE IGEN AVSS0 ADIO AVDD0 CLTV FILO AVSS3 VSS AVDD3 DOUT VDD PCO FILI ASYO ASYI RFAC BIAS SSTP DFCT MIRR MDP LOCK FOK SFDR VSS TEST FRDR FE VC COUT SE XTSL TES1 SRDR TFDR FFDR TRDR 2 1 70 71 68 69 66 67 64 65 62 61 63 73 74 72 75 76 77 78 79 80 4 XRST 3 SQCK SQSO 5 9 8 7 6 56 60 53 54 55 59 57 58 51 52 48 49 50 47 44 45 46 43 41 42 XLAT CLOK SENS SYSM DATA XUGF XPCK GFS C2PO WFCK 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 32 33 30 31 36 37 34 35 39 40 38 28 27 29 SPOA ATSK SCLK VDD SCOR SPOB XLON XTAI XVDD EMPH AVDD1 AOUT1 AIN1 XTAO XVSS AIN2 AOUT2 AVDD2 RMUT LOUT2 LOUT1 BCK LRCK PCMD LMUT AVSS1 AVSS2 CPU INTERFACE SERVO AUTO SEQUENCER SERIAL IN INTERFACE OVER SAMPLING DIGITAL FILTER 3rd ORDER NOISE SHAPER PWM PWM EFM DEMODULATOR TIMING LOGIC DIGITAL OUT D/A INTERFACE DIGITAL PLL ASYMMETRY CORRECTION CLOCK GENERATOR MIRR, DFCT, FOK DETECTOR DIGITAL CLV SUBCODE PROCESSOR SERVO INTERFACE SERVO DSP FOCUS SERVO TRACKING SERVO SLED SERVO PWM GENERATOR FOCUS PWM GENERATOR TRACKING PWM GENERATOR SLED PWM GENERATOR 16K RAM ERROR CORRECTOR INTERNAL BUS A/D CONVERTER OPERATIONAL AMPLIFIER ANALOG SWITCH www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 65 – IC103 CXA2568M-T6 APC PD AMP APC LD AMP RF SUMMING AMP RF EQ AMP FOCUS ERROR AMP TRACKING ERROR AMP VC BUFFER VCC 50µA VEE VEE VC VC VC VC VC VC VC VC VC VC VCC VEE VCC VEE VEE VC VCC LC/PD LD ON HOLD SW AGC CONT RFTC RF I RF O RFE TE FE RF BOT HOLD AGC VTH LD PD A B C D VEE F E VC 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 + – + – + – + – + – + – + – VCC + – + – + – + – + – + – + – + – + – – MOTOR (TURN) Board – IC701 M54641L REG CONTROL INPUT AMP. INPUT AMP. 1 2 3 4 5 6 7 8 POWER AMP. POWER AMP. VCC OUT1 IN2 REFERENCE GND IN1 OUT2 VCC – MOTOR (SLIDE) Board – IC801 BA6286N POWER SAVE CONTROL LOGIC TSD 1 2 3 4 5 6 7 8 9 10 GND RIN VREF OUT2 RNF GND OUT1 VM VCC FIN www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 66 – – AUDIO Board – IC602 µPC1330HA 1 2 3 4 5 6 7 8 9 INVERTER COMPARATER SW R1 GND SW P1 CONT GND VCC SW P2 GND SW R2 – PANEL Board – IC603 BA3830F F01 R02 R01 LINE NF LINE IN REFERENCE CURRENT REFERENCE CURRENT RESET BAND PASS FILTER DET 17 RESET 18 F02 16 F03 15 F04 14 F05 13 F06 12 REC LEVEL 11 VCC 10 4 3 2 1 + – REC NF REC IN 6 RESET C 7 BIAS C 8 GND 9 5 + – IC604 NJU3716M-T2 OUTPUT CIRCUIT LATCH CIRCUIT SHIFT REGISTER CONTROL CIRCUIT 20 21 19 23 24 22 18 17 16 15 14 13 4 3 2 1 6 P7 P8 P9 P10 P11 VSS P12 P13 P14 P15 P16 7 SO 8 9 10 11 12 5 VDD P6 P5 P4 P3 P2 VSS P1 CLR STB CLK DATA IC711 M65850FP (HCD-GRX70J: Saudi Arabia) OSCILLATOR 1/2 VCC AUTO RESET LPF1 MAIN CONTROL A/D 20KBIT SRAM LPF2 D/A 1 2 3 4 5 6 7 8 9 10 14 13 12 11 CLOCK RESET MO MI D1 DO0 DO1 VCC CLOCK REF OP2IN OP2OUT LPF2IN LPF2OUT LPF1IN LPF1OUT OP1OUT OP1IN CC1 CC2 GND www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 67 – 7-25. IC PIN FUNCTION DESCRIPTION • MAIN BOARD IC501 M30622MA-A07FP (SYSTEM CONTROLLER (CD MECHANISM CONTROL)) Pin No. Pin Name I/O Description 1 STK-MUTE O Power amplifier on/off selection signal output terminal “L”: standby mode, “H”: on 2 POWER O Power on/off control signal output for the audio system (+5V) and deck, panel, audio system (+7V) “L”: standby mode, “H”: power on 3 F-RELAY O Relay drive signal output for the speaker protect “H”: relay on 4 R-RELAY O Relay drive signal output for the speaker protect “H”: relay on Not used (open) 5 CD-POWER O Power on/off control signal output for the CD mechanism deck section “L”: standby mode, “H”: power on 6 LINE-MUTE O Line muting on/off control signal output terminal “L”: muting on 7 DBFB-H/L O DBFB normal/high selection signal output to the M62493FP (IC101) “L”: DBFB high, “H”: DBFB low 8 BYTE I External data bus line byte selection signal input terminal Fixed at “L” in this set 9 CNVSS — Ground terminal 10 XC-IN I Sub system clock input terminal (32.768 kHz) 11 XC-OUT O Sub system clock output terminal (32.768 kHz) 12 RESET I System reset signal input from the reset signal generator (IC502) “L”: reset For several hundreds msec. after the power supply rises, “L” is input, then it changes to “H” 13 X-OUT O Main system clock output terminal (16 MHz) 14 VSS — Ground terminal 15 X-IN I Main system clock input terminal (16 MHz) 16 VCC — Power supply terminal (+5V) 17 NMI I Non-maskable interrupt input terminal Fixed at “H” in this set 18 WAKE UP I Wakeup control signal input from the fluorescent indicator tube driver (IC601) “H” active 19 SCOR I Subcode sync (S0+S1) detection signal input from the CXD2587Q (IC101) on the CD block 20 RDS-INT I Serial data transfer clock signal input terminal Not used (fixed at “L”) 21 RDS-DATA I Serial data input terminal Not used (fixed at “L”) 22 AC-CUT I AC off detection signal input from the reset signal generator (IC502) “L”: AC cut checked 23 PL-CLK O Serial data transfer clock signal output to the pro-logic circuit Not used (open) 24 PL-DATA O Serial data output to the pro-logic circuit Not used (open) 25 PL-LAT O Serial data latch pulse output to the pro-logic circuit Not used (open) 26 TIMER LED O LED drive signal output of the TIMER SELECT indicator (D632) “H”: LED on 27 PROTECTOR I Protect on/off detection signal input from the speaker protect circuit “L”: protect on, “H”: protect off 28 V MUTE O Muting on/off control signal output terminal “L”: muting off Not used (open) 29 IIC-CLK I/O Communication data reading clock signal input or transfer clock signal output with the fluo- rescent indicator tube driver (IC601) 30 IIC-DATA I/O Communication data bus with the fluorescent indicator tube driver (IC601) 31 NCO O Not used (open) 32 SQ-DATA I Subcode Q data input from the CXD2587Q (IC101) on the CD block 33 SQ-CLK O Subcode Q data reading clock signal output to the CXD2587Q (IC101) on the CD block 34 SW MODE O Not used (open) 35 CD-DATA O Serial data output to the CXD2587Q (IC101) on the CD block 36 RY-SW I Connection detect signal input of the headphone jack (J701) “L”: no connected, “H”: headphone connected 37 CD-CLK O Serial data transfer clock signal output to the CXD2587Q (IC101) on the CD block 38 493-LATCH O Serial data latch pulse output to the M62493FP (IC101) 39 STBY LED O LED drive signal output of the I/u indicator (D754) “H”: LED on (standby mode) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 68 – *1 Disc tray turn motor (M701) control *2 Disc tray slide motor (M801) control Stop Counter- clockwise Clockwise Brake Stop Table In Table Out Brake TBL-L (pin ^£) “H” “L” “H” “L” LOAD-OUT (pin ^§) “L” “L” “H” “H” TBL-R (pin ^∞) “H” “H” “L” “L” LOAD-IN (pin ^¶) “L” “H” “L” “H” Terminal Mode Terminal Mode Pin No. Pin Name I/O Description 40 VC L+R/L–R O Virtual cinema L+R/L–R selection signal output terminal Not used (open) 41 VC BYPASS O Virtual cinema bypass control signal output terminal Not used (open) 42 FL SW O Filament on/off selection signal output for the fluorescent indicator tube (FL601) “L”: on, “H”: off Used for the HCD-RXD80 model only 43 STBY RELAY O Main power on/off control signal output terminal “L”: standby mode, “H”: power on Used for the HCD-RXD80 model only 44 BASS FREQ. O Sync bass frequency normal/high selection signal output to the M62493FP (IC101) “L”: sync bass off (normal), “H”: sync bass high 45 FUNC SEL1 O Not used (open) 46 FUNC SEL0 O Not used (open) 47 493-DATA O Serial data output to the M62493FP (IC101) 48 493-CLK O Serial data transfer clock signal output to the M62493FP (IC101) 49 ST-MUTE O Tuner muting control signal output to the FM/AM tuner unit “H”: muting on 50 STEREO I FM stereo detection signal input from the FM/AM tuner unit “L”: stereo 51 TUNED I Tuning detection signal input from the FM/AM tuner unit “L”: tuned 52 ST-CE O PLL chip enable signal output to the FM/AM tuner unit 53 ST-DOUT O PLL serial data output to the FM/AM tuner unit 54 ST-DIN I PLL serial data input from the FM/AM tuner unit 55 ST-CLK O PLL serial data transfer clock signal output to the FM/AM tuner unit 56 SENSE I Internal status detection monitor input from the CXD2587Q (IC101) on the CD block 57 HOLD O Laser power control signal output to the CXA2568M (IC103) on the CD block 58 XLT O Serial data latch pulse output to the CXD2587Q (IC101) on the CD block 59 XRST O Reset signal output to the CXD2587Q (IC101) and BA5974FP (IC102) on the CD block “L”: reset 60 DISC-SENS I Disc status detection signal input from the disc sensor (IC703) 61 TBL-SENS I Disc tray status detection signal input from the disc tray sensor (IC702) 62 VCC — Power supply terminal (+5V) 63 TBL-L O Motor drive signal output to the disc tray turn motor driver (IC701) “L” active *1 64 VSS — Ground terminal 65 TBL-R O Motor drive signal output to the disc tray turn motor driver (IC701) “L” active *1 66 LOAD-OUT O Motor drive signal output to the disc tray slide motor driver (IC801) “H” active *2 67 LOAD-IN O Motor drive signal output to the disc tray slide motor driver (IC801) “H” active *2 68 to 70 ENC3 to ENC1 I Detection signal input from the disc tray address detect rotary encoder (S811) 71 OUT-OPEN I Detection signal input from the disc tray open/close detect switch (S801) “L”: open, “H”: close 72 B-TRG O Deck-B side trigger plunger drive signal output terminal “H”: plunger on 73 A-TRG O Deck-A side trigger plunger drive signal output terminal “H”: plunger on 74 CAPM-CNT2 O Capstan motor (M1) drive signal output terminal “H” active *3 75 CAPM-CNT1 O Capstan motor (M1) drive signal output terminal “H” active *3 76 CAP-M-H/L O High/normal speed selection signal output of the capstan motor (M1) “L”: normal speed, “H”: high speed www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 69 – *3 Capstan motor (M1) control Stop Forward Direction Reverse Direction Brake CAPM-CNT1 (pin &∞) “L” “L” “H” “H” CAPM-CNT2 (pin &¢) “L” “H” “L” “H” Terminal Mode Pin No. Pin Name I/O Description 77 AMS-IN I Whether a music is present or not from HA12215F (IC301) is detected at automatic music sensor “L”: music is present, “H”: music is not present 78 TC-MUTE O Line muting on/off selection signal output to the HA12215F (IC301) “L”: muting off, “H”: muting on 79 R/P-PASS O Recording/playback/pass selection signal output to the HA12215F (IC301) “L”: recording mode, “H”: pass, “Hi-z”: playback mode 80 NR-ON/OFF O Dolby NR on/off selection signal output to the HA12215F (IC301) “L”: dolby off, “H”: dolby on 81 REC-MUTE O Recording muting on/off selection signal output to the HA12215F (IC301) “L”: muting on, “H”: muting off 82 BIAS O Recording bias on/off selection signal output to the HA12215F (IC301) “L”: bias off, “H”: bias on 83 EQ-H/N O Normal/high speed selection signal output to the HA12215F (IC301) “L”: normal speed, “H”: high speed 84 PB-A/B O Deck-A/B selection signal output to the HA12215F (IC301) “L”: deck-A, “H”: deck-B 85 ALC-ON/OFF O Automatic limiter control signal output to the HA12215F (IC301) “L”: limiter on 86 B-PLAY-SW I Detection input from the deck- B play detect switch (S1002) “H”: deck-B play 87 A-PLAY-SW I Detection input from the deck- A play detect switch (S1001) “H”: deck-A play 88 A-HALF I Detection input from the deck-A cassette detect switch (S1003) “L”: cassette in, “H”: no cassette 89 B-HALF I Detection input from the deck-B half detect switch (S1006) 90 B-SHUT I Shut off detection signal input from the deck-B side reel pulse detector (IC1002) 91 A-SHUT I Shut off detection signal input from the deck-A side reel pulse detector (IC1001) 92 SOFT-TEST O Output terminal for the software test (open) 93 HEADPHONE MUTE O Muting on/off control signal output terminal “L”: muting on Not used (open) 94 KEY/CD ADJ I Setting terminal for the CD adjustment mode Not used (open) 95 MODEL-IN I Destination setting terminal 96 AVSS — Ground terminal (for A/D conversion) 97 SPEC-IN I Setting terminal for the version 98 AVREF I Reference voltage (+5V) input terminal (for A/D conversion) 99 AVCC — Power supply terminal (+5V) (for A/D conversion) 100 TC-RELAY O Recording/playback select signal output to the REC/PB switch (IC602) “L”: playback, “H”: recording www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 70 – • PANEL BOARD IC601 TMP88CS76F-6004 (FLUORESCENT INDICATOR TUBE DRIVER, KEY CONTROL) Pin No. Pin Name I/O Description 1 SIRCS I Remote control signal input from the remote control receiver (IC602) 2 JOG-A I Jog dial pulse input from the rotary encoder (S601 JOG) (A phase input) 3 LED SCK O Serial data transfer clock signal output to the LED driver (IC604) 4 LED LAT O Serial data latch pulse signal output to the LED driver (IC604) 5 LED DATA O Serial data output to the LED driver (IC604) 6 PAD LAT O Not used (open) 7 L SEL O LED selection signal output terminal 8 JOG-B I Jog dial pulse input from the rotary encoder (S601 JOG) (B phase input) 9 VOL-A I Jog dial pulse input from the rotary encoder (S602 VOLUME) (A phase input) 10 VOL-B I Jog dial pulse input from the rotary encoder (S602 VOLUME) (B phase input) 11 KEY0 I Key input terminal (A/D input) (S625 to S630) REC PAUSE/START, HI-DUB, CD SYNC, LOOP, DISPLAY, SPECTRUM ANALYZER keys input 12 KEY1 I Key input terminal (A/D input) (S611 to S624) SYNC BASS, SYNC EQ, KARAOKE PON/MPX, NON-STOP, SURROUND, DBFB, ENTER/NEXT, + ), – 0, GROOVE, FLASH, REPEAT STEREO/MONO, PLAY MODE DOLBY NR, EDIT DIRECTION TUNER MEMORY keys input 13 KEY2 I Key input terminal (A/D input) (S638 to S642 and S751 to S757) TIMER SELECT, P FILE MEMORY, GEQ CONTROL, FILE SELECT, EFFECT, I/u, (STANDBY) POWER SAVE DEMO, DISC 1/2/3, DISC SKIP EX-CHANGE, § keys input 14 KEY3 I Key input terminal (A/D input) (S643 to S651) TUNER/BAND, ( P CD, p, ( TAPE B, 9 TAPE B, ( TAPE A, 9 TAPE A, FUNCTION, CLOCK/TIMER SET keys input 15 GRAD L2 O Not used (open) 16 S LOW FREQ (BPF0) I Spectrum analyzer drive (super low frequency) signal input from the spectrum analyzer band- pass filter (IC603) (for 40 Hz) 17 BPF1 I Spectrum analyzer drive (low frequency) signal input from the spectrum analyzer band-pass filter (IC603) (for 100 Hz) 18 BPF2 I Spectrum analyzer drive (low and middle frequency) signal input from the spectrum analyzer band-pass filter (IC603) (for 400 Hz) 19 BPF3 I Spectrum analyzer drive (middle and high frequency) signal input from the spectrum analyzer band-pass filter (IC603) (for 2 kHz) 20 BPF4 I Spectrum analyzer drive (high frequency) signal input from the spectrum analyzer band-pass filter (IC603) (for 6 kHz) 21 ALL BAND (L+R) I Spectrum analyzer drive signal input from the spectrum analyzer band-pass filter (IC603) (for VACS, non-stop signal) 22 WAKE UP O Wakeup control signal output to the system controller (IC501) “H” active 23 VSS — Ground terminal 24 VASS — Ground terminal (for A/D conversion) 25 VAREF I Reference voltage (+5V) input terminal (for A/D conversion) 26 VDD — Power supply terminal (+5V) 27 to 32 G18 to G13 O Grid drive signal output to the fluorescent indicator tube (FL601) 33 to 40 G12 to G5 O Grid drive signal output to the fluorescent indicator tube (FL601) 41 VDD — Power supply terminal (+5V) 42 to 44 G4 to G2 O Grid drive signal output to the fluorescent indicator tube (FL601) 45 G1 O Grid drive signal output to the fluorescent indicator tube (FL601) 46 to 67 S1 to S22 O Segment drive signal output to the fluorescent indicator tube (FL601) 68 VKK — Power supply terminal (–30V) (for fluorescent indicator tube drive) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 71 – Pin No. Pin Name I/O Description 69 VDD — Power supply terminal (+5V) 70 XIN I System clock input terminal (12.5 MHz) 71 VSS — Ground terminal 72 XOUT O System clock output terminal (12.5 MHz) 73 RESET I System reset signal input from the reset signal generator (IC502) “L”: reset For several hundreds msec. after the power supply rises, “L” is input, then it changes to “H” 74 CH O Not used (open) 75 BUSY I Not used (fixed at “L”) 76 TEST I Connected to ground 77 GRAD R1 O Not used (open) 78 I2C DATA I/O Communication data bus with the system controller (IC501) 79 I2C CLK I/O Communication data reading clock signal input or transfer clock signal output with the system controller (IC501) 80 GRAD R2 O Not used (open) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 72 – (1) COVER SECTION SECTION 8 EXPLODED VIEWS Les composants identifiés par une marque ! sont critiquens pour la sécurité. Ne les remplacer que par une pièce portant le numéro spécifié. The components identified by mark ! or dotted line with mark ! are critical for safety. Replace only with part number specified. • Items marked “*” are not stocked since they are seldom required for routine service. Some delay should be anticipated when ordering these items. • The mechanical parts with no reference num- ber in the exploded views are not supplied. • Hardware (# mark) list is given in the last of the electrical parts list. NOTE: • -XX and -X mean standardized parts, so they may have some difference from the original one. • Color Indication of Appearance Parts Example: KNOB, BALANCE (WHITE) . . . (RED) ↑ ↑ Parts Color Cabinet's Color Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 1 X-4950-832-1 HOLDER (R) ASSY, CASSETTE (SILVER) 1 X-4950-971-1 HOLDER (R) ASSY, CASSETTE (GRAY) 2 X-4950-828-1 HOLDER (L) ASSY, CASSETTE (SILVER) 2 X-4950-970-1 HOLDER (L) ASSY, CASSETTE (GRAY) 3 X-4950-756-1 PANEL ASSY, LOADING (SILVER) 3 X-4951-575-1 PANEL ASSY, LOADING (GRX70J) 3 X-4951-580-1 PANEL ASSY, LOADING (RXD80) 3 X-4951-581-1 PANEL ASSY, LOADING (GRX70: E3) 4 3-363-099-01 SCREW (CASE 3 TP2) (3X8) (GRAY) 4 3-363-099-11 SCREW (CASE 3 TP2) (3X8) (SILVER) 5 3-363-099-41 SCREW (CASE 3 TP2) (3X12) (GRAY) 5 3-363-099-71 SCREW (CASE 3 TP2) (3X12) (SILVER) * 6 4-214-443-01 COVER (SILVER) * 6 4-215-752-61 COVER (GRAY) 7 4-951-620-01 SCREW (2.6X8), +BVTP 8 4-215-062-01 DAMPER 9 4-985-642-01 CUSHION 10 4-219-087-01 SPRING, TENSION TCM-230AWR2 not supplied not supplied #5 #3 #3 #3 #4 #4 front panel section not supplied #5 #6 7 7 8 9 8 1 10 10 2 3 4 5 5 4 6 #1 • Abbreviation AR : Argentine model AUS : Australian model CND : Canadian model E2 : 120 V AC Area in E model E3 : 240 V AC Area in E model EA3 : Saudi Arabia model MX : Mexican model SP : Singapore model TH : Thai model TW : Taiwan model www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 73 – Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark (2) FRONT PANEL SECTION 51 X-4950-869-1 PANEL ASSY, FRONT (GRX70: E2, SP, TH, TW, MX, AR, AUS) 51 X-4951-598-1 PANEL ASSY, FRONT (GRX70: E3/GRX70J: E3) 51 X-4951-599-1 PANEL ASSY, FRONT (GRX70J: EA3) 51 X-4951-600-1 PANEL ASSY, FRONT (RXD80) 52 4-930-336-61 FOOT (FELT) 53 4-962-708-71 EMBLEM (4-A), SONY 54 4-214-775-11 SPRING, PUSH CATCHER RETURN 55 4-214-761-11 CATCHER (B), PUSH 56 4-214-760-11 CATCHER (A), PUSH 57 4-214-384-11 KNOB (VOL) (SILVER) 57 4-214-384-51 KNOB (VOL) (GRAY) 58 4-214-383-11 KNOB (JOG) (SILVER) 58 4-214-383-51 KNOB (JOG) (GRAY) * 59 4-996-716-01 HOLDER (CDM) 60 4-951-620-01 SCREW (2.6X8), +BVTP 61 4-214-385-11 KNOB (MIC) (SILVER) 61 4-214-385-51 KNOB (MIC) (GRAY) * 62 A-4417-808-A PANEL BOARD, COMPLETE (GRX70/RXD80) 62 A-4419-985-A PANEL BOARD, COMPLETE (GRX70J: E3) 62 A-4426-002-A PANEL BOARD, COMPLETE (GRX70J: EA3) * 63 A-4417-727-A CD SW BOARD, COMPLETE 64 1-773-188-11 WIRE (FLAT TYPE) (23 CORE) 51 54 54 55 56 52 57 58 53 59 60 60 60 60 59 61 61 62 63 60 64 supplied with S602 supplied with S601 EA3 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 74 – (3) CHASSIS SECTION 111 111 112 EA3, SP, TW AUS CND E2, E3, TH, MX E3 RXD80 RXD80 GRX70/ GRX70J EA3, SP, TW, AR 101 111 111 112 110 102 104 105 107 not supplied T951 #10 #10 #9 #2 #2 #2 #3 #2 #2 #2 #2 M501 #2 #2 CDM38LH-5BD32L not supplied 109 103 108 113 106 T11 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 75 – Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 101 4-965-822-01 FOOT * 102 1-672-369-11 TRANS BOARD * 103 3-703-244-00 BUSHING (2104), CORD (GRX70: SP, TW, AUS/GRX70J: EA3/RXD80) 103 3-703-571-11 BUSHING (S) (4516), CORD (GRX70: E2, E3, TH, MX, AR/GRX70J: E3) 104 1-773-042-11 WIRE (FLAT TYPE) (17 CORE) (14cm) (GRX70: E3, TW, AR, AUS/RXD80) 104 1-773-043-11 WIRE (FLAT TYPE) (17 CORE) (15cm) (GRX70: E2, SP, TH, MX/GRX70J) 105 1-773-024-11 WIRE (FLAT TYPE) (15 CORE) (32cm) 106 1-783-570-11 WIRE (FLAT TYPE) (19 CORE) * 107 A-4417-812-A MAIN BOARD, COMPLETE (GRX70: E2, MX, AR) * 107 A-4419-007-A MAIN BOARD, COMPLETE (GRX70: E3, SP, TW) 107 A-4419-816-A MAIN BOARD, COMPLETE (RXD80) 107 A-4419-828-A MAIN BOARD, COMPLETE (GRX70: TH, AUS) 107 A-4419-991-A MAIN BOARD, COMPLETE (GRX70J: E3) * 107 A-4426-000-A MAIN BOARD, COMPLETE (GRX70J: EA3) * 108 4-214-456-61 PANEL, BACK (GRX70: TH) * 108 4-215-169-01 PANEL, BACK (GRX70: E2, AR) * 108 4-215-169-11 PANEL, BACK (GRX70: SP) * 108 4-215-169-21 PANEL, BACK (GRX70: MX) * 108 4-215-169-31 PANEL, BACK (GRX70J: EA3) * 108 4-216-169-51 PANEL, BACK (GRX70J: E3) * 108 4-219-987-01 PANEL, BACK (RXD80) * 108 4-219-987-21 PANEL, BACK (GRX70: E3) * 108 4-219-987-31 PANEL, BACK (GRX70: TW) * 108 4-219-987-41 PANEL, BACK (GRX70: AUS) 109 1-769-977-11 WIRE (FLAT TYPE) (13 CORE) (GRX70: E2, TH, MX, AR, AUS/ RXD80) 109 1-773-009-11 WIRE (FLAT TYPE) (15 CORE) (15cm) (GRX70: E3, SP, TW/GRX70J) 110 1-233-544-14 TUNER PACK (RXD80) 110 1-233-545-11 TUNER (FM/AM) (GRX70: TH, AUS) 110 1-233-545-14 TUNER PACK (GRX70: MX, AR) 110 1-233-546-11 TUNER (FM/MW/SW) (GRX70: E3, SP, TW/GRX70J) 110 1-693-453-11 TUNER (FM/AM) (GRX70: E2) !111 1-575-651-11 CORD, POWER (GRX70: SP, TW/GRX70J: EA3) !111 1-575-653-11 CORD, POWER (GRX70: E2, E3, TH, MX/GRX70J: E3) !111 1-690-608-11 CORD, POWER (GRX70: AUS) !111 1-690-609-21 CORD, POWER (RXD80: CND) !111 1-783-941-21 CORD, POWER (GRX70: AR) !112 1-569-007-11 ADAPTOR, CONVERSION 2P (GRX70: E3/GRX70J: E3) !112 1-569-008-21 ADAPTOR, CONVERSION 2P (GRX70: SP, TW/GRX70J: EA3) * 113 A-4417-729-A SUB TRANS BOARD, COMPLETE (RXD80) M501 1-698-792-11 FAN, DC !T11 1-433-587-11 TRANSFORMER, POWER (RXD80) !T951 1-433-561-11 TRANSFORMER, POWER (GRX70/GRX70J) !T951 1-433-562-21 TRANSFORMER, POWER (RXD80) The components identified by mark ! or dotted line with mark ! are critical for safety. Replace only with part num- ber specified. Les composants identifiés par une marque ! sont critiques pour la sécurité. Ne les remplacer que par une pièce portant le numéro spécifié. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 76 – Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark (4) CD MECHANISM DECK SECITON-1 (CDM38LH-5BD32L) 201 4-981-789-11 BRACKET (2), YOKE 202 4-977-945-01 TRAY (TURN) 203 X-4946-665-1 SHAFT ASSY, WORM 204 4-977-943-01 BELT (TURN) (1.2) 205 4-977-956-01 WHEEL, WORM * 206 1-658-577-11 MOTOR (TURN) BOARD 207 4-988-162-01 ROLLER 208 4-977-941-01 BEARING (WORM) * 209 1-658-576-11 SENSOR BOARD 210 4-934-376-01 SHAFT (ROLLER) 211 4-981-187-01 COLLAR (WORM) 212 4-977-944-01 TRAY (SLIDE) M701 A-4672-004-A MOTOR ASSY (DISC TRAY TURN) #8 M701 #2 #2 201 201 202 203 211 204 205 206 208 209 210 207 212 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 77 – Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark (5) CD MECHANISM DECK SECITON-2 (CDM38LH-5BD32L) 251 4-981-789-11 BRACKET (2), YOKE 252 4-977-954-01 PULLEY (SL) 253 4-977-953-01 GEAR (SL-A) 254 4-977-955-01 GEAR (SL-B) 255 4-977-942-01 BELT (SL) (1.4) 256 X-4946-667-1 CAM ASSY, BU 257 1-452-925-21 MAGNET ASSY 258 1-776-042-11 WIRE (FLAT TYPE) (8 CORE) * 259 1-658-575-11 CONNECTOR BOARD * 260 X-4946-668-1 CHASSIS (CDM) ASSY 261 4-985-672-01 SCREW (+PTPWHM2.6), FLOATING * 262 1-658-578-11 MOTOR (SLIDE) BOARD 263 4-982-447-01 SPRING (BU), COMPRESSION 264 4-951-620-41 SCREW (2.6), +BVTP 265 X-4949-570-1 HOLDER (BU) ASSY 266 4-989-494-01 SCREW (SLIDER), STEP 267 4-989-492-11 SLIDER (38) 268 4-989-819-02 SPRING, TENSION 269 4-989-491-11 COVER (2), LENS 270 4-993-142-21 PULLEY (L), PRESS M801 A-4672-004-A MOTOR ASSY (DISC TRAY SLIDE) S811 1-473-335-11 ENCODER, ROTARY (BU, TRAY ADDRESS DET) 251 251 251 252 253 254 255 257 270 256 258 259 260 261 261 BU-5BD32L #2 #2 S811 M801 not supplied 262 263 264 265 263 266 269 268 267 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 78 – Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark (6) BASE UNIT SECTION (BU-5BD32L) !301 8-820-020-02 OPTICAL PICK-UP KSS-213D/Q-NP 302 1-769-069-11 WIRE (FLAT TYPE) (16 CORE) 303 4-917-567-01 GEAR (M) 304 4-951-940-01 INSULATOR (BU) 305 4-917-565-01 SHAFT, SLED 306 4-917-564-01 GEAR (P), FLATNESS * 307 A-4724-486-A BD BOARD, COMPLETE 308 4-951-620-01 SCREW (2.6X8), +BVTP 309 3-713-786-51 SCREW +P 2X3 M101 X-4917-523-4 MOTOR ASSY (SPINDLE) M102 X-4917-504-1 MOTOR ASSY (SLED) M102 M101 301 302 303 309 304 305 304 308 307 306 The components identified by mark ! or dotted line with mark ! are critical for safety. Replace only with part num- ber specified. Les composants identifiés par une marque ! sont critiques pour la sécurité. Ne les remplacer que par une pièce portant le numéro spécifié. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 79 – (7) TAPE MECHANISM DECK SECTION-1 (TCM-230AWR2) Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 401 3-376-464-11 SCREW (+PTT 2.6X6), GROUND POINT 402 3-036-914-01 RIVET 403 3-016-574-11 SPRING (HEAD), TENSION 404 X-3374-156-4 PINCH LEVER (REV) ASSY 405 X-3374-155-4 PINCH LEVER (FWD) ASSY 406 3-016-564-01 BASE (PINCH LEVER FWD) 407 3-016-565-01 BASE (PINCH LEVER REV) 408 3-026-892-01 SPRING (CASSETTE), LEAF * 409 A-2007-731-A AUDIO BOARD, COMPLETE 410 3-032-809-02 SPRING (L), TORSION 411 3-016-572-01 LEVER (EJECT PREVENTION L) 412 3-032-810-02 SPRING (R), TORSION 413 3-016-573-01 LEVER (EJECT PREVENTION R) HP101 A-2056-681-A DECK (A) ASSY, HEAD HRPE101A-2056-682-A DECK (B) ASSY, HEAD 401 402 402 403 403 404 410 411 404 405 405 412 413 406 406 407 408 408 407 HRPE101 HP101 409 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 80 – Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark (8) TAPE MECHANISM DECK SECTION-2 (TCM-230AWR2) * 451 X-3374-214-3 CHASSIS ASSY, MAIN 452 3-016-570-01 BELT (CAPSTAN) 453 3-016-569-01 BELT (TENSION) 454 3-017-360-01 BRACKET (MOTOR) 455 X-3376-497-1 FLYWHEEL (FWD) ASSY 456 X-3374-235-1 FLYWHEEL (REV) ASSY 457 X-3374-238-1 PULLEY ASSY, TENSION 458 3-024-405-01 BELT (FR2) 459 A-2004-629-A MECHANICAL BLOCK ASSY 460 3-016-566-01 SLIDER, REVERSE * 461 A-2007-732-A LEAF SW BOARD, COMPLETE 462 3-016-575-11 SPRING, TORSION 463 3-019-208-01 WASHER, STOPPER 464 3-027-453-01 SPRING (GROUND), TENSION 465 3-030-823-01 SCREW (+BVTT) (2X3.5) M1 A-2004-628-A MOTOR ASSY, CAPSTAN 451 452 452 453 454 455 455 456 456 457 458 458 459 459 464 460 460 461 462 463 M1 #10 #11 #12 #10 #10 #10 #7 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 81 – Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark AUDIO * A-2007-731-A AUDIO BOARD, COMPLETE ********************** < CAPACITOR > C301 1-162-289-31 CERAMIC 390PF 10% 50V C302 1-126-968-11 ELECT 100uF 20% 6.3V C303 1-162-282-31 CERAMIC 100PF 10% 50V C304 1-130-483-00 MYLAR 0.01uF 5% 50V C305 1-107-715-11 ELECT 22uF 20% 16V C311 1-162-289-31 CERAMIC 390PF 10% 50V C313 1-162-282-31 CERAMIC 100PF 10% 50V C314 1-130-487-00 MYLAR 0.022uF 5% 50V C315 1-126-233-11 ELECT 22uF 20% 50V C331 1-137-427-11 FILM 120PF 5% 50V C332 1-162-288-31 CERAMIC 330PF 10% 50V C333 1-162-209-31 CERAMIC 27PF 5% 50V C401 1-162-289-31 CERAMIC 390PF 10% 50V C402 1-126-968-11 ELECT 100uF 20% 6.3V C403 1-162-282-31 CERAMIC 100PF 10% 50V C404 1-130-483-00 MYLAR 0.01uF 5% 50V C405 1-107-715-11 ELECT 22uF 20% 16V C411 1-162-289-31 CERAMIC 390PF 10% 50V C413 1-162-282-31 CERAMIC 100PF 10% 50V C414 1-130-487-00 MYLAR 0.022uF 5% 50V C415 1-126-233-11 ELECT 22uF 20% 50V C431 1-137-427-11 FILM 120PF 5% 50V C432 1-162-288-31 CERAMIC 330PF 10% 50V C433 1-162-209-31 CERAMIC 27PF 5% 50V C601 1-104-396-11 ELECT 10uF 20% 16V C602 1-104-396-11 ELECT 10uF 20% 16V C611 1-104-396-11 ELECT 10uF 20% 16V C612 1-104-396-11 ELECT 10uF 20% 16V C621 1-137-150-11 FILM 0.01uF 5% 100V C622 1-126-961-11 ELECT 2.2uF 20% 50V C623 1-136-155-00 FILM 0.015uF 5% 50V C624 1-130-481-00 MYLAR 0.0068uF 5% 50V C625 1-130-481-00 MYLAR 0.0068uF 5% 50V C627 1-124-903-11 ELECT 1uF 20% 50V C628 1-136-153-00 FILM 0.01uF 5% 50V C642 1-104-664-11 ELECT 47uF 20% 16V < CONNECTOR > CN601 1-568-834-11 SOCKET, CONNECTOR 15P < IC > IC601 8-759-111-44 IC uPC4570C-1 IC602 8-759-143-54 IC uPC1330HA IC611 8-759-111-44 IC uPC4570C-1 < COIL > L331 1-410-780-11 INDUCTOR 27mH L431 1-410-780-11 INDUCTOR 27mH L601 1-414-193-41 INDUCTOR 220uH L602 1-414-193-41 INDUCTOR 220uH < TRANSISTOR > Q621 8-729-142-46 TRANSISTOR 2SC2001-LK Q622 8-729-142-46 TRANSISTOR 2SC2001-LK Q623 8-729-801-93 TRANSISTOR 2SD1387 < RESISTOR > R301 1-247-881-00 CARBON 120K 5% 1/4W R302 1-249-409-11 CARBON 220 5% 1/4W R303 1-249-433-11 CARBON 22K 5% 1/4W R304 1-247-889-00 CARBON 270K 5% 1/4W R305 1-247-858-11 CARBON 13K 5% 1/4W R311 1-247-881-00 CARBON 120K 5% 1/4W R312 1-247-807-31 CARBON 100 5% 1/4W R314 1-247-882-11 CARBON 130K 5% 1/4W R315 1-247-850-11 CARBON 6.2K 5% 1/4W R331 1-249-430-11 CARBON 12K 5% 1/4W R401 1-247-881-00 CARBON 120K 5% 1/4W R402 1-249-409-11 CARBON 220 5% 1/4W R403 1-249-433-11 CARBON 22K 5% 1/4W R404 1-247-889-00 CARBON 270K 5% 1/4W R405 1-247-858-11 CARBON 13K 5% 1/4W R411 1-247-881-00 CARBON 120K 5% 1/4W R412 1-247-807-31 CARBON 100 5% 1/4W R414 1-247-882-11 CARBON 130K 5% 1/4W R415 1-247-850-11 CARBON 6.2K 5% 1/4W R431 1-249-430-11 CARBON 12K 5% 1/4W R601 1-249-409-11 CARBON 220 5% 1/4W SECTION 9 ELECTRICAL PARTS LIST NOTE: • Due to standardization, replacements in the parts list may be different from the parts speci- fied in the diagrams or the components used on the set. • -XX and -X mean standardized parts, so they may have some difference from the original one. • RESISTORS All resistors are in ohms. METAL: Metal-film resistor. METAL OXIDE: Metal oxide-film resistor. F: nonflammable • Items marked “*” are not stocked since they are seldom required for routine service. Some delay should be anticipated when order- ing these items. • SEMICONDUCTORS In each case, u: µ, for example: uA. . : µA. . uPA. . : µPA. . uPB. . : µPB. . uPC. . : µPC. . uPD. . : µPD. . • CAPACITORS uF: µF • COILS uH: µH Les composants identifiés par une marque ! sont critiquens pour la sécurité. Ne les remplacer que par une pièce portant le numéro spécifié. The components identified by mark ! or dotted line with mark ! are critical for safety. Replace only with part number specified. When indicating parts by reference number, please include the board. • Abbreviation AR : Argentine model AUS : Australian model CND : Canadian model E2 : 120 V AC Area in E model E3 : 240 V AC Area in E model EA3 : Saudi Arabia model MX : Mexican model SP : Singapore model TH : Thai model TW : Taiwan model www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 82 – Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark R602 1-249-409-11 CARBON 220 5% 1/4W R608 1-249-409-11 CARBON 220 5% 1/4W R609 1-249-433-11 CARBON 22K 5% 1/4W R611 1-249-409-11 CARBON 220 5% 1/4W R612 1-249-409-11 CARBON 220 5% 1/4W !R621 1-212-851-00 FUSIBLE 5.6 5% 1/4W F !R622 1-212-851-00 FUSIBLE 5.6 5% 1/4W F R623 1-249-432-11 CARBON 18K 5% 1/4W R624 1-249-432-11 CARBON 18K 5% 1/4W R625 1-249-429-11 CARBON 10K 5% 1/4W < VARIABLE RESISTOR > RV301 1-238-598-11 RES, ADJ, CARBON 2.2K RV311 1-238-598-11 RES, ADJ, CARBON 2.2K RV341 1-241-768-11 RES, ADJ, CARBON 220K RV401 1-238-598-11 RES, ADJ, CARBON 2.2K RV411 1-238-598-11 RES, ADJ, CARBON 2.2K RV441 1-241-768-11 RES, ADJ, CARBON 220K < TRANSFORMER > T621 1-423-980-11 TRANSFORMER, BIAS OSCILLATION ************************************************************ * A-4724-486-A BD BOARD, COMPLETE ****************** < CAPACITOR > C101 1-163-005-11 CERAMIC CHIP 470PF 10% 50V C102 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V C103 1-163-005-11 CERAMIC CHIP 470PF 10% 50V C104 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V C108 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V C109 1-163-011-11 CERAMIC CHIP 0.0015uF 10% 50V C110 1-164-182-11 CERAMIC CHIP 0.0033uF 10% 50V C111 1-163-251-11 CERAMIC CHIP 100PF 5% 50V C112 1-163-038-00 CERAMIC CHIP 0.1uF 25V C113 1-163-038-00 CERAMIC CHIP 0.1uF 25V C114 1-163-038-00 CERAMIC CHIP 0.1uF 25V C115 1-126-607-11 ELECT CHIP 47uF 20% 4V C116 1-126-607-11 ELECT CHIP 47uF 20% 4V C117 1-126-209-11 ELECT CHIP 100uF 20% 4V C118 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V C119 1-163-235-11 CERAMIC CHIP 22PF 5% 50V C121 1-163-038-00 CERAMIC CHIP 0.1uF 25V C122 1-126-206-11 ELECT CHIP 100uF 20% 6.3V C123 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V C124 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V C125 1-163-038-00 CERAMIC CHIP 0.1uF 25V C126 1-163-038-00 CERAMIC CHIP 0.1uF 25V C127 1-128-065-11 ELECT CHIP 68uF 20% 10V C128 1-163-038-00 CERAMIC CHIP 0.1uF 25V C129 1-163-031-11 CERAMIC CHIP 0.01uF 50V C130 1-164-346-11 CERAMIC CHIP 1uF 16V C131 1-124-779-00 ELECT CHIP 10uF 20% 16V C133 1-164-346-11 CERAMIC CHIP 1uF 16V C140 1-164-346-11 CERAMIC CHIP 1uF 16V C141 1-164-346-11 CERAMIC CHIP 1uF 16V C143 1-163-038-00 CERAMIC CHIP 0.1uF 25V C151 1-163-235-11 CERAMIC CHIP 22PF 5% 50V C153 1-163-038-00 CERAMIC CHIP 0.1uF 25V C154 1-110-501-11 CERAMIC CHIP 0.33uF 10% 16V C156 1-163-235-11 CERAMIC CHIP 22PF 5% 50V C157 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V C159 1-163-019-00 CERAMIC CHIP 0.0068uF 10% 50V C161 1-126-206-11 ELECT CHIP 100uF 20% 6.3V C162 1-126-205-11 ELECT CHIP 47uF 20% 6.3V C163 1-126-206-11 ELECT CHIP 100uF 20% 6.3V C165 1-163-038-00 CERAMIC CHIP 0.1uF 25V C167 1-163-235-11 CERAMIC CHIP 22PF 5% 50V C168 1-163-235-11 CERAMIC CHIP 22PF 5% 50V C171 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V C172 1-163-123-00 CERAMIC CHIP 180PF 5% 50V C181 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V C182 1-163-123-00 CERAMIC CHIP 180PF 5% 50V < CONNECTOR > CN101 1-778-874-11 CONNECTOR,FFC (LIF(NON-ZIF)) 19P CN102 1-777-937-11 CONNECTOR, FFC/FPC 16P < FERRITE BEAD > FB101 1-500-445-21 FERRITE 0uH FB103 1-500-445-21 FERRITE 0uH < IC > IC101 8-752-386-85 IC CXD2587Q IC102 8-759-549-28 IC BA5974FP-E2 IC103 8-752-085-51 IC CXA2568M-T6 < TRANSISTOR > Q101 8-729-010-08 TRANSISTOR MSB710-R < RESISTOR > R101 1-216-077-00 METAL CHIP 15K 5% 1/10W R102 1-216-097-91 RES,CHIP 100K 5% 1/10W R103 1-216-077-00 METAL CHIP 15K 5% 1/10W R104 1-216-085-00 METAL CHIP 33K 5% 1/10W R105 1-216-073-00 METAL CHIP 10K 5% 1/10W R106 1-216-049-11 RES,CHIP 1K 5% 1/10W R107 1-216-073-00 METAL CHIP 10K 5% 1/10W R108 1-216-061-00 METAL CHIP 3.3K 5% 1/10W R109 1-216-121-00 RES,CHIP 1M 5% 1/10W R110 1-216-025-00 RES,CHIP 100 5% 1/10W R111 1-216-121-00 RES,CHIP 1M 5% 1/10W R113 1-216-121-00 RES,CHIP 1M 5% 1/10W R114 1-216-073-00 METAL CHIP 10K 5% 1/10W R116 1-216-001-00 METAL CHIP 10 5% 1/10W R117 1-216-049-11 RES,CHIP 1K 5% 1/10W R119 1-216-041-00 METAL CHIP 470 5% 1/10W R123 1-216-073-00 METAL CHIP 10K 5% 1/10W R124 1-216-097-91 RES,CHIP 100K 5% 1/10W R131 1-216-033-00 METAL CHIP 220 5% 1/10W R143 1-216-103-00 METAL CHIP 180K 5% 1/10W R144 1-216-103-00 METAL CHIP 180K 5% 1/10W R147 1-216-069-00 METAL CHIP 6.8K 5% 1/10W AUDIO BD The components identified by mark ! or dotted line with mark ! are critical for safety. Replace only with part num- ber specified. Les composants identifiés par une marque ! sont critiques pour la sécurité. Ne les remplacer que par une pièce portant le numéro spécifié. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 83 – Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark R148 1-216-001-00 METAL CHIP 10 5% 1/10W R149 1-216-001-00 METAL CHIP 10 5% 1/10W R158 1-216-111-00 METAL CHIP 390K 5% 1/10W R159 1-216-101-00 METAL CHIP 150K 5% 1/10W R161 1-216-308-00 METAL CHIP 4.7 5% 1/10W R162 1-216-101-00 METAL CHIP 150K 5% 1/10W R171 1-216-078-00 RES,CHIP 16K 5% 1/10W R172 1-216-073-00 METAL CHIP 10K 5% 1/10W R173 1-216-077-00 METAL CHIP 15K 5% 1/10W R181 1-216-078-00 RES,CHIP 16K 5% 1/10W R182 1-216-073-00 METAL CHIP 10K 5% 1/10W R183 1-216-077-00 METAL CHIP 15K 5% 1/10W < NETWORK RESISTER > RN101 1-233-576-11 RES, CHIP NETWORK 100 RN102 1-233-576-11 RES, CHIP NETWORK 100 < SWITCH > S101 1-572-085-11 SWITCH, LEAF (LIMIT) < VIBRATOR > X101 1-767-408-21 VIBRATOR, CRYSTAL (16.9344MHz) ************************************************************ * A-4417-727-A CD SW BOARD, COMPLETE ********************** < DIODE > D751 8-719-056-13 LED SML79423C-TP15 (DISC 1) D752 8-719-056-13 LED SML79423C-TP15 (DISC 2) D753 8-719-056-13 LED SML79423C-TP15 (DISC 3) D754 8-719-063-93 LED SLR325VC-N-T32 (1/u) < RESISTOR > R751 1-249-417-11 CARBON 1K 5% 1/4W R752 1-249-418-11 CARBON 1.2K 5% 1/4W R753 1-249-420-11 CARBON 1.8K 5% 1/4W R754 1-249-422-11 CARBON 2.7K 5% 1/4W R755 1-247-843-11 CARBON 3.3K 5% 1/4W R756 1-249-425-11 CARBON 4.7K 5% 1/4W R757 1-249-427-11 CARBON 6.8K 5% 1/4W R758 1-247-804-11 CARBON 75 5% 1/4W R759 1-249-407-11 CARBON 150 5% 1/4W R760 1-247-804-11 CARBON 75 5% 1/4W R761 1-249-407-11 CARBON 150 5% 1/4W R762 1-247-804-11 CARBON 75 5% 1/4W R763 1-249-407-11 CARBON 150 5% 1/4W R764 1-249-414-11 CARBON 560 5% 1/4W < SWITCH > S751 1-762-875-21 SWITCH, KEYBOARD (1/u) S752 1-762-875-21 SWITCH, KEYBOARD ((STANDBY) POWER SAVE DEMO) S753 1-762-875-21 SWITCH, KEYBOARD (DISC 1) S754 1-762-875-21 SWITCH, KEYBOARD (DISC 2) S755 1-762-875-21 SWITCH, KEYBOARD (DISC 3) S756 1-762-875-21 SWITCH, KEYBOARD (DISC SKIP EX-CHANGE) S757 1-762-875-21 SWITCH, KEYBOARD (§) ************************************************************ * 1-658-575-11 CONNECTOR BOARD ***************** < CONNECTOR > * CN701 1-568-946-11 PIN, CONNECTOR 8P CN702 1-750-550-11 CONNECTOR, FFC/FPC 8P < TRANSISTOR > Q701 8-729-900-80 TRANSISTOR DTC114ES < RESISTOR > R703 1-249-435-11 CARBON 33K 5% 1/4W R704 1-249-429-11 CARBON 10K 5% 1/4W R705 1-249-417-11 CARBON 1K 5% 1/4W ************************************************************ * A-2007-732-A LEAF SW BOARD, COMPLETE ************************ < CAPACITOR > C1001 1-107-716-11 ELECT 33uF 20% 10V < CONNECTOR > CN1001 1-568-860-11 SOCKET, CONNECTOR 17P < DIODE > D1001 8-719-911-19 DIODE 1SS119 D1002 8-719-911-19 DIODE 1SS119 < CONNECTOR > * DM1001 1-784-581-11 HOLDER, CABLE (2.5MM PITCH) 4P < PHOTO INTERRUPTER > IC1001 8-749-014-38 PHOTO INTERRUPTER SG-264 IC1002 8-749-014-38 PHOTO INTERRUPTER SG-264 < TRANSISTOR > Q1001 8-729-029-56 TRANSISTOR DTA144ESA < RESISTOR > R907 1-247-879-11 CARBON 100K 5% 1/4W R1001 1-249-409-11 CARBON 220 5% 1/4W R1002 1-249-409-11 CARBON 220 5% 1/4W R1003 1-249-414-11 CARBON 560 5% 1/4W R1004 1-247-834-11 CARBON 1.3K 5% 1/4W R1005 1-247-818-11 CARBON 300 5% 1/4W R1006 1-247-864-11 CARBON 24K 5% 1/4W R1007 1-247-856-00 CARBON 11K 5% 1/4W R1008 1-249-417-11 CARBON 1K 5% 1/4W < VARIABLE RESISTOR > RV1001 1-241-785-11 RES, ADJ, CARBON 10K RV1002 1-241-785-11 RES, ADJ, CARBON 10K BD CD SW CONNECTOR LEAF SW www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 84 – Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark < SWITCH > S1001 1-570-953-11 SWITCH, PUSH (1 KEY) (DECK A PLAY) S1002 1-570-953-11 SWITCH, PUSH (1 KEY) (DECK B PLAY) S1003 1-771-333-11 SWITCH, LEAF (DECK A HALF) S1004 1-771-205-11 SWITCH, LEAF (DECK A 120/70) S1005 1-771-205-11 SWITCH, LEAF (DECK A REC) S1006 1-771-333-11 SWITCH, LEAF (DECK B HALF) S1008 1-771-205-11 SWITCH, LEAF (DECK B 120/70) S1009 1-771-205-11 SWITCH, LEAF (DECK B REC) ************************************************************ * A-4417-812-A MAIN BOARD, COMPLETE (GRX70: E2, MX, AR) * A-4419-007-A MAIN BOARD, COMPLETE (GRX70: E3, SP, TW) A-4419-816-A MAIN BOARD, COMPLETE (RXD80) A-4419-828-A MAIN BOARD, COMPLETE (GRX70: TH, AUS) A-4419-991-A MAIN BOARD, COMPLETE (GRX70J: E3) * A-4426-000-A MAIN BOARD, COMPLETE (GRX70J: EA3) ********************* 7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S < CAPACITOR > C104 1-164-159-11 CERAMIC 0.1uF 50V C111 1-137-195-11 FILM 0.56uF 5% 50V C112 1-136-158-00 FILM 0.027uF 5% 50V C113 1-136-167-00 FILM 0.15uF 5% 50V C114 1-130-480-00 MYLAR 0.0056uF 5% 50V C115 1-136-159-00 FILM 0.033uF 5% 50V C116 1-130-473-00 MYLAR 0.0015uF 5% 50V C117 1-136-153-00 FILM 0.01uF 5% 50V C118 1-162-288-31 CERAMIC 330PF 10% 50V C119 1-130-479-00 MYLAR 0.0047uF 5% 50V C120 1-130-477-00 MYLAR 0.0033uF 5% 50V C121 1-126-964-11 ELECT 10uF 20% 50V C122 1-162-291-31 CERAMIC 560PF 10% 50V C123 1-136-169-00 FILM 0.22uF 5% 50V C124 1-136-169-00 FILM 0.22uF 5% 50V C125 1-126-964-11 ELECT 10uF 20% 50V C131 1-104-664-11 ELECT 47uF 20% 16V C132 1-104-664-11 ELECT 47uF 20% 16V C135 1-126-964-11 ELECT 10uF 20% 50V C141 1-126-959-11 ELECT 0.47uF 20% 50V C161 1-137-195-11 FILM 0.56uF 5% 50V C162 1-136-158-00 FILM 0.027uF 5% 50V C163 1-136-167-00 FILM 0.15uF 5% 50V C164 1-130-480-00 MYLAR 0.0056uF 5% 50V C165 1-136-159-00 FILM 0.033uF 5% 50V C166 1-130-473-00 MYLAR 0.0015uF 5% 50V C167 1-136-153-00 FILM 0.01uF 5% 50V C168 1-162-288-31 CERAMIC 330PF 10% 50V C169 1-130-479-00 MYLAR 0.0047uF 5% 50V C170 1-130-477-00 MYLAR 0.0033uF 5% 50V C171 1-126-964-11 ELECT 10uF 20% 50V C172 1-162-291-31 CERAMIC 560PF 10% 50V C173 1-136-169-00 FILM 0.22uF 5% 50V C174 1-136-169-00 FILM 0.22uF 5% 50V C175 1-126-964-11 ELECT 10uF 20% 50V C176 1-136-495-11 FILM 0.068uF 5% 50V C177 1-136-153-00 FILM 0.01uF 5% 50V C193 1-126-964-11 ELECT 10uF 20% 50V C197 1-164-159-11 CERAMIC 0.1uF 50V C301 1-126-960-11 ELECT 1uF 20% 50V C302 1-130-479-00 MYLAR 0.0047uF 5% 50V C303 1-136-165-00 FILM 0.1uF 5% 50V C304 1-136-165-00 FILM 0.1uF 5% 50V C305 1-126-964-11 ELECT 10uF 20% 50V C306 1-126-960-11 ELECT 1uF 20% 50V C307 1-126-959-11 ELECT 0.47uF 20% 50V C308 1-126-964-11 ELECT 10uF 20% 50V C309 1-137-194-81 FILM 0.47uF 5% 50V C310 1-162-290-31 CERAMIC 470PF 10% 50V C311 1-126-964-11 ELECT 10uF 20% 50V C312 1-126-959-11 ELECT 0.47uF 20% 50V C313 1-162-294-31 CERAMIC 0.001uF 10% 50V C314 1-126-964-11 ELECT 10uF 20% 50V C315 1-126-963-11 ELECT 4.7uF 20% 50V C316 1-104-665-11 ELECT 100uF 20% 10V C317 1-104-665-11 ELECT 100uF 20% 10V C320 1-162-290-31 CERAMIC 470PF 10% 50V C333 1-162-600-11 CERAMIC 0.0047uF 30% 16V C334 1-162-600-11 CERAMIC 0.0047uF 30% 16V C351 1-126-960-11 ELECT 1uF 20% 50V C352 1-130-479-00 MYLAR 0.0047uF 5% 50V C353 1-136-165-00 FILM 0.1uF 5% 50V C354 1-136-165-00 FILM 0.1uF 5% 50V C355 1-126-964-11 ELECT 10uF 20% 50V C356 1-126-960-11 ELECT 1uF 20% 50V C357 1-126-959-11 ELECT 0.47uF 20% 50V C358 1-126-964-11 ELECT 10uF 20% 50V C359 1-137-194-81 FILM 0.47uF 5% 50V C382 1-104-665-11 ELECT 100uF 20% 10V C390 1-126-935-11 ELECT 470uF 20% 6.3V C391 1-161-494-00 CERAMIC 0.022uF 25V C392 1-126-916-11 ELECT 1000uF 20% 6.3V C393 1-161-494-00 CERAMIC 0.022uF 25V C394 1-126-925-11 ELECT 470uF 20% 10V C396 1-126-961-11 ELECT 2.2uF 20% 50V C397 1-126-961-11 ELECT 2.2uF 20% 50V C410 1-126-963-11 ELECT 4.7uF 20% 50V C411 1-162-306-11 CERAMIC 0.01uF 20% 16V C412 1-107-717-11 ELECT 47uF 20% 50V C432 1-104-665-11 ELECT 100uF 20% 10V C433 1-126-961-11 ELECT 2.2uF 20% 50V C437 1-126-968-11 ELECT 100uF 20% 50V C501 1-126-964-11 ELECT 10uF 20% 50V C502 1-164-159-11 CERAMIC 0.1uF 50V C503 1-136-165-00 FILM 0.1uF 5% 50V C504 1-126-926-11 ELECT 1000uF 20% 10V C508 1-109-889-11 ELECT 1uF 20% 50V C610 1-102-953-00 CERAMIC 18PF 5% 50V C611 1-102-514-11 CERAMIC 22PF 5% 50V C614 1-162-306-11 CERAMIC 0.01uF 20% 16V C616 1-104-665-11 ELECT 100uF 20% 10V LEAF SW MAIN www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 85 – Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark C662 1-162-306-11 CERAMIC 0.01uF 20% 16V C664 1-104-665-11 ELECT 100uF 20% 10V C698 1-162-306-11 CERAMIC 0.01uF 20% 16V C699 1-104-665-11 ELECT 100uF 20% 10V C801 1-126-963-11 ELECT 4.7uF 20% 50V (GRX70/GRX70J) C801 1-128-581-11 ELECT 4.7uF 20% 100V (RXD80) C802 1-162-290-31 CERAMIC 470PF 10% 50V C803 1-162-282-31 CERAMIC 100PF 10% 50V C804 1-104-665-11 ELECT 100uF 20% 10V C807 1-136-495-11 FILM 0.068uF 5% 50V C808 1-136-495-11 FILM 0.068uF 5% 50V C809 1-128-560-11 ELECT 22uF 20% 100V C810 1-128-578-11 ELECT 1uF 20% 100V C811 1-162-306-11 CERAMIC 0.01uF 20% 16V C812 1-162-306-11 CERAMIC 0.01uF 20% 16V C841 1-127-811-11 ELECT 3300uF 20% 50V (GRX70/GRX70J) C842 1-127-752-11 ELECT 3300uF 20% 63V (RXD80) C842 1-127-814-11 ELECT 3300uF 20% 80V (GRX70/GRX70J) C843 1-136-165-00 FILM 0.1uF 5% 50V (GRX70/GRX70J) C844 1-130-777-00 FILM 0.1uF 10% 100V C851 1-126-963-11 ELECT 4.7uF 20% 50V (GRX70/GRX70J) C851 1-128-581-11 ELECT 4.7uF 20% 100V (RXD80) C852 1-162-290-31 CERAMIC 470PF 10% 50V C853 1-162-282-31 CERAMIC 100PF 10% 50V C854 1-104-665-11 ELECT 100uF 20% 10V C857 1-136-495-11 FILM 0.068uF 5% 50V C858 1-136-495-11 FILM 0.068uF 5% 50V C859 1-128-560-11 ELECT 22uF 20% 100V C881 1-126-967-11 ELECT 47uF 20% 50V C891 1-127-811-11 ELECT 3300uF 20% 50V (GRX70/GRX70J) C892 1-127-752-11 ELECT 3300uF 20% 63V (RXD80) C892 1-127-814-11 ELECT 3300uF 20% 80V (GRX70/GRX70J) C893 1-136-165-00 FILM 0.1uF 5% 50V (GRX70/GRX70J) C894 1-130-777-00 FILM 0.1uF 10% 100V C901 1-136-165-00 FILM 0.1uF 5% 50V C902 1-126-936-11 ELECT 3300uF 20% 16V (RXD80) C902 1-126-937-11 ELECT 4700uF 20% 16V (GRX70/GRX70J) C903 1-126-933-11 ELECT 100uF 20% 16V C904 1-104-664-11 ELECT 47uF 20% 16V C905 1-104-665-11 ELECT 100uF 20% 10V C906 1-136-165-00 FILM 0.1uF 5% 50V C907 1-128-548-11 ELECT 4700uF 20% 25V C909 1-126-964-11 ELECT 10uF 20% 50V C910 1-104-665-11 ELECT 100uF 20% 10V C911 1-126-964-11 ELECT 10uF 20% 50V C912 1-126-926-11 ELECT 1000uF 20% 10V C913 1-126-964-11 ELECT 10uF 20% 50V C914 1-126-767-11 ELECT 1000uF 20% 16V C915 1-104-664-11 ELECT 47uF 20% 16V C916 1-162-306-11 CERAMIC 0.01uF 20% 16V C917 1-126-933-11 ELECT 100uF 20% 16V C951 1-136-165-00 FILM 0.1uF 5% 50V C952 1-126-768-11 ELECT 2200uF 20% 16V C953 1-126-933-11 ELECT 100uF 20% 16V C955 1-104-665-11 ELECT 100uF 20% 10V C956 1-136-165-00 FILM 0.1uF 5% 50V < CONNECTOR > CN303 1-784-776-11 CONNECTOR, FFC 15P CN304 1-784-778-11 CONNECTOR, FFC 17P CN371 1-784-774-11 CONNECTOR, FFC 13P (GRX70: E2, TH, MX, AR/RXD80) CN371 1-784-776-11 CONNECTOR, FFC 15P (GRX70: E3, SP, TW, AUS/GRX70J) CN391 1-784-741-11 CONNECTOR, FFC 19P CN392 1-785-334-11 PIN, CONNECTOR (LIGHT ANGLE) 8P CN393 1-785-335-11 PIN, CONNECTOR (LIGHT ANGLE) 9P * CN403 1-564-518-11 PLUG, CONNECTOR 3P CN501 1-784-784-11 CONNECTOR, FFC 23P < DIODE > D141 8-719-911-19 DIODE 1SS119 D191 8-719-911-19 DIODE 1SS119 D331 8-719-911-19 DIODE 1SS119 D333 8-719-911-19 DIODE 1SS119 D334 8-719-911-19 DIODE 1SS119 D335 8-719-911-19 DIODE 1SS119 D401 8-719-911-19 DIODE 1SS119 D403 8-719-911-19 DIODE 1SS119 D405 8-719-024-99 DIODE 11ES2-NTA2B D406 8-719-024-99 DIODE 11ES2-NTA2B D407 8-719-024-99 DIODE 11ES2-NTA2B D411 8-719-911-19 DIODE 1SS119 D501 8-719-024-99 DIODE 11ES2-NTA2B D502 8-719-911-19 DIODE 1SS119 D503 8-719-911-19 DIODE 1SS119 D504 8-719-911-19 DIODE 1SS119 D505 8-719-911-19 DIODE 1SS119 D506 8-719-911-19 DIODE 1SS119 D509 8-719-911-19 DIODE 1SS119 D607 8-719-911-19 DIODE 1SS119 D644 8-719-911-19 DIODE 1SS119 D801 8-719-911-19 DIODE 1SS119 D802 8-719-160-64 DIODE RD16F-B1 D803 8-719-911-19 DIODE 1SS119 D831 8-719-302-38 DIODE RBV-602-01 D832 8-719-302-38 DIODE RBV-602-01 (GRX70/GRX70J) D851 8-719-911-19 DIODE 1SS119 D852 8-719-160-64 DIODE RD16F-B1 D881 8-719-911-19 DIODE 1SS119 D901 8-719-024-99 DIODE 11ES2-NTA2B D902 8-719-024-99 DIODE 11ES2-NTA2B D903 8-719-024-99 DIODE 11ES2-NTA2B D904 8-719-024-99 DIODE 11ES2-NTA2B MAIN www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 86 – Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark D905 8-719-933-36 DIODE HZS6B1L D906 8-719-911-19 DIODE 1SS119 D907 8-719-024-99 DIODE 11ES2-NTA2B D908 8-719-024-99 DIODE 11ES2-NTA2B D909 8-719-024-99 DIODE 11ES2-NTA2B D910 8-719-024-99 DIODE 11ES2-NTA2B D915 8-719-935-69 DIODE HZS11B1LTA D921 8-719-911-19 DIODE 1SS119 (GRX70/GRX70J) D922 8-719-911-19 DIODE 1SS119 (GRX70/GRX70J) D923 8-719-911-19 DIODE 1SS119 (GRX70/GRX70J) D924 8-719-024-99 DIODE 11ES2-NTA2B (GRX70/GRX70J) D925 8-719-024-99 DIODE 11ES2-NTA2B (GRX70/GRX70J) < FERRITE BEAD > FB301 1-412-473-21 FERRITE 0uH FB302 1-412-473-21 FERRITE 0uH < IC > IC101 8-759-571-54 IC M62493FP IC301 8-759-495-26 IC HA12215 IC381 8-749-923-04 IC TOTX178 (CD DIGITAL OUT OPTICAL) IC501 8-759-588-89 IC M30622MA-A07FP IC502 8-759-635-63 IC M51943BSL IC801 8-749-015-37 IC STK411-240E (GRX70/GRX70J) IC801 8-749-015-45 IC STK407-090E (RXD80) IC901 8-759-604-86 IC M5F7807L IC902 8-759-231-53 IC TA7805S IC903 8-759-088-08 IC uPC7812AHF < JACK > J101 1-774-411-11 JACK, PIN 6P (VIDEO (AUDIO) IN, MD IN/OUT) J191 1-774-785-11 JACK, PIN 1P (SUPER WOOFER) < COIL > L381 1-410-521-11 INDUCTOR 100uH L392 1-410-521-11 INDUCTOR 100uH L501 1-410-509-11 INDUCTOR 10uH < TRANSISTOR > Q111 8-729-119-78 TRANSISTOR 2SC403SP-51 Q112 8-729-119-78 TRANSISTOR 2SC403SP-51 Q113 8-729-141-30 TRANSISTOR 2SC3623A-LK Q161 8-729-119-78 TRANSISTOR 2SC403SP-51 Q162 8-729-119-78 TRANSISTOR 2SC403SP-51 Q163 8-729-141-30 TRANSISTOR 2SC3623A-LK Q191 8-729-141-30 TRANSISTOR 2SC3623A-LK Q192 8-729-900-63 TRANSISTOR DTA124ES Q201 8-729-900-36 TRANSISTOR DTC124ES Q251 8-729-900-36 TRANSISTOR DTC124ES Q331 8-729-118-00 TRANSISTOR 2SB1116-L Q332 8-729-900-80 TRANSISTOR DTC114ES Q333 8-729-118-00 TRANSISTOR 2SB1116-L Q334 8-729-900-80 TRANSISTOR DTC114ES Q335 8-729-900-80 TRANSISTOR DTC114ES Q336 8-729-116-59 TRANSISTOR 2SB1068TP Q337 8-729-045-21 TRANSISTOR 2SD1513TP-LK Q338 8-729-422-57 TRANSISTOR UN4111 Q339 8-729-900-80 TRANSISTOR DTC114ES Q340 8-729-116-59 TRANSISTOR 2SB1068TP Q341 8-729-045-21 TRANSISTOR 2SD1513TP-LK Q342 8-729-422-57 TRANSISTOR UN4111 Q343 8-729-900-80 TRANSISTOR DTC114ES Q401 8-729-119-77 TRANSISTOR 2SA1175-FEK Q402 8-729-111-29 TRANSISTOR 2SD1616A-K Q411 8-729-141-30 TRANSISTOR 2SC3623A-LK Q412 8-729-900-63 TRANSISTOR DTA124ES Q431 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA Q432 8-729-140-82 TRANSISTOR 2SA988-PAFAEA Q433 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA Q434 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA Q435 8-729-900-36 TRANSISTOR DTC124ES Q436 8-729-119-77 TRANSISTOR 2SA1175-FEK Q437 8-729-119-79 TRANSISTOR 2SC2785-FEK Q439 8-729-119-79 TRANSISTOR 2SC2785-FEK Q471 8-729-141-30 TRANSISTOR 2SC3623A-LK Q501 8-729-119-78 TRANSISTOR 2SC403SP-51 Q508 8-729-900-63 TRANSISTOR DTA124ES Q509 8-729-900-63 TRANSISTOR DTA124ES Q801 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA Q803 8-729-140-82 TRANSISTOR 2SA988-PAFAEA Q804 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA Q831 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA Q832 8-729-119-79 TRANSISTOR 2SC2785-FEK Q851 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA Q881 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA Q901 8-729-209-15 TRANSISTOR 2SD2012 Q902 8-729-119-78 TRANSISTOR 2SC403SP-51 Q903 8-729-900-36 TRANSISTOR DTC124ES Q904 8-729-900-36 TRANSISTOR DTC124ES Q905 8-729-040-20 TRANSISTOR RT1P137L-TP Q907 8-729-040-20 TRANSISTOR RT1P137L-TP Q908 8-729-900-36 TRANSISTOR DTC124ES Q909 8-729-026-68 TRANSISTOR 2SD2525 (TP) Q913 8-729-119-78 TRANSISTOR 2SC403SP-51 Q914 8-729-119-77 TRANSISTOR 2SA1175-FEK Q923 8-729-900-36 TRANSISTOR DTC124ES Q951 8-729-141-83 TRANSISTOR 2SB1094-LK Q952 8-729-119-77 TRANSISTOR 2SA1175-FEK < RESISTOR > R101 1-249-417-11 CARBON 1K 5% 1/4W R102 1-249-417-11 CARBON 1K 5% 1/4W R103 1-249-417-11 CARBON 1K 5% 1/4W R111 1-249-429-11 CARBON 10K 5% 1/4W R112 1-247-895-00 CARBON 470K 5% 1/4W R113 1-247-894-11 CARBON 430K 5% 1/4W R114 1-249-415-11 CARBON 680 5% 1/4W R115 1-249-433-11 CARBON 22K 5% 1/4W R116 1-247-887-00 CARBON 220K 5% 1/4W R117 1-249-429-11 CARBON 10K 5% 1/4W R118 1-249-437-11 CARBON 47K 5% 1/4W R119 1-249-421-11 CARBON 2.2K 5% 1/4W R120 1-249-441-11 CARBON 100K 5% 1/4W R121 1-249-429-11 CARBON 10K 5% 1/4W R124 1-249-421-11 CARBON 2.2K 5% 1/4W MAIN www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 87 – Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark R125 1-247-843-11 CARBON 3.3K 5% 1/4W R126 1-249-421-11 CARBON 2.2K 5% 1/4W R130 1-249-433-11 CARBON 22K 5% 1/4W R131 1-247-807-31 CARBON 100 5% 1/4W R132 1-247-807-31 CARBON 100 5% 1/4W R133 1-247-807-31 CARBON 100 5% 1/4W R141 1-249-433-11 CARBON 22K 5% 1/4W R142 1-249-433-11 CARBON 22K 5% 1/4W R143 1-249-417-11 CARBON 1K 5% 1/4W R144 1-249-441-11 CARBON 100K 5% 1/4W R145 1-247-903-00 CARBON 1M 5% 1/4W R151 1-249-417-11 CARBON 1K 5% 1/4W R152 1-249-417-11 CARBON 1K 5% 1/4W R153 1-249-417-11 CARBON 1K 5% 1/4W R161 1-249-429-11 CARBON 10K 5% 1/4W R162 1-247-895-00 CARBON 470K 5% 1/4W R163 1-247-894-11 CARBON 430K 5% 1/4W R164 1-249-415-11 CARBON 680 5% 1/4W R165 1-249-433-11 CARBON 22K 5% 1/4W R166 1-247-887-00 CARBON 220K 5% 1/4W R167 1-249-429-11 CARBON 10K 5% 1/4W R168 1-249-437-11 CARBON 47K 5% 1/4W R169 1-249-421-11 CARBON 2.2K 5% 1/4W R170 1-249-441-11 CARBON 100K 5% 1/4W R171 1-249-429-11 CARBON 10K 5% 1/4W R178 1-249-421-11 CARBON 2.2K 5% 1/4W R190 1-249-441-11 CARBON 100K 5% 1/4W R196 1-249-417-11 CARBON 1K 5% 1/4W R197 1-249-441-11 CARBON 100K 5% 1/4W R198 1-249-417-11 CARBON 1K 5% 1/4W R199 1-249-429-11 CARBON 10K 5% 1/4W R201 1-247-888-11 CARBON 240K 5% 1/4W R202 1-247-903-00 CARBON 1M 5% 1/4W R251 1-247-888-11 CARBON 240K 5% 1/4W R252 1-247-903-00 CARBON 1M 5% 1/4W R301 1-249-435-11 CARBON 33K 5% 1/4W R302 1-249-421-11 CARBON 2.2K 5% 1/4W R303 1-247-807-31 CARBON 100 5% 1/4W R304 1-247-807-31 CARBON 100 5% 1/4W R305 1-249-421-11 CARBON 2.2K 5% 1/4W R306 1-249-428-11 CARBON 8.2K 5% 1/4W R307 1-249-428-11 CARBON 8.2K 5% 1/4W R308 1-249-425-11 CARBON 4.7K 5% 1/4W R309 1-249-433-11 CARBON 22K 5% 1/4W R311 1-247-903-00 CARBON 1M 5% 1/4W R312 1-247-884-11 CARBON 160K 5% 1/4W R313 1-249-441-11 CARBON 100K 5% 1/4W R315 1-249-429-11 CARBON 10K 5% 1/4W R316 1-249-432-11 CARBON 18K 5% 1/4W R317 1-249-429-11 CARBON 10K 5% 1/4W R318 1-249-429-11 CARBON 10K 5% 1/4W R319 1-247-893-11 CARBON 390K 5% 1/4W R321 1-249-422-11 CARBON 2.7K 5% 1/4W R322 1-249-428-11 CARBON 8.2K 5% 1/4W R324 1-247-876-11 CARBON 75K 5% 1/4W R325 1-247-876-11 CARBON 75K 5% 1/4W R326 1-249-437-11 CARBON 47K 5% 1/4W R327 1-249-437-11 CARBON 47K 5% 1/4W R328 1-249-437-11 CARBON 47K 5% 1/4W R329 1-249-417-11 CARBON 1K 5% 1/4W R330 1-249-425-11 CARBON 4.7K 5% 1/4W R331 1-249-425-11 CARBON 4.7K 5% 1/4W R332 1-249-415-11 CARBON 680 5% 1/4W R333 1-249-421-11 CARBON 2.2K 5% 1/4W R334 1-249-415-11 CARBON 680 5% 1/4W R335 1-249-421-11 CARBON 2.2K 5% 1/4W R336 1-249-437-11 CARBON 47K 5% 1/4W R337 1-249-417-11 CARBON 1K 5% 1/4W R338 1-249-411-11 CARBON 330 5% 1/4W R339 1-249-437-11 CARBON 47K 5% 1/4W R340 1-249-437-11 CARBON 47K 5% 1/4W R341 1-249-411-11 CARBON 330 5% 1/4W R342 1-249-437-11 CARBON 47K 5% 1/4W R343 1-249-417-11 CARBON 1K 5% 1/4W R351 1-249-435-11 CARBON 33K 5% 1/4W R352 1-249-421-11 CARBON 2.2K 5% 1/4W R353 1-247-807-31 CARBON 100 5% 1/4W R354 1-247-807-31 CARBON 100 5% 1/4W R355 1-249-421-11 CARBON 2.2K 5% 1/4W R356 1-249-428-11 CARBON 8.2K 5% 1/4W R357 1-249-428-11 CARBON 8.2K 5% 1/4W R358 1-249-425-11 CARBON 4.7K 5% 1/4W R359 1-249-435-11 CARBON 33K 5% 1/4W R391 1-247-807-31 CARBON 100 5% 1/4W R392 1-247-807-31 CARBON 100 5% 1/4W R393 1-249-435-11 CARBON 33K 5% 1/4W R394 1-249-435-11 CARBON 33K 5% 1/4W R406 1-249-437-11 CARBON 47K 5% 1/4W R407 1-249-437-11 CARBON 47K 5% 1/4W R408 1-249-425-11 CARBON 4.7K 5% 1/4W R409 1-249-441-11 CARBON 100K 5% 1/4W R410 1-249-421-11 CARBON 2.2K 5% 1/4W !R411 1-215-893-11 METAL OXIDE 1.5K 5% 2W F (RXD80) !R411 1-215-894-11 METAL OXIDE 2.2K 5% 2W F (GRX70/GRX70J) R413 1-249-402-11 CARBON 56 5% 1/4W R414 1-249-417-11 CARBON 1K 5% 1/4W R415 1-249-429-11 CARBON 10K 5% 1/4W R416 1-249-437-11 CARBON 47K 5% 1/4W R417 1-249-417-11 CARBON 1K 5% 1/4W R421 1-260-089-11 CARBON 150 5% 1/2W R422 1-260-089-11 CARBON 150 5% 1/2W R431 1-249-438-11 CARBON 56K 5% 1/4W R432 1-249-437-11 CARBON 47K 5% 1/4W R434 1-249-433-11 CARBON 22K 5% 1/4W R435 1-249-435-11 CARBON 33K 5% 1/4W R437 1-249-429-11 CARBON 10K 5% 1/4W R438 1-249-429-11 CARBON 10K 5% 1/4W R439 1-249-425-11 CARBON 4.7K 5% 1/4W R440 1-249-433-11 CARBON 22K 5% 1/4W R441 1-249-435-11 CARBON 33K 5% 1/4W R443 1-249-417-11 CARBON 1K 5% 1/4W R471 1-260-089-11 CARBON 150 5% 1/2W R472 1-260-089-11 CARBON 150 5% 1/2W R473 1-249-402-11 CARBON 56 5% 1/4W The components identified by mark ! or dotted line with mark ! are critical for safety. Replace only with part num- ber specified. Les composants identifiés par une marque ! sont critiques pour la sécurité. Ne les remplacer que par une pièce portant le neméro spécifié. MAIN www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 88 – Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark R474 1-249-417-11 CARBON 1K 5% 1/4W R481 1-260-089-11 CARBON 150 5% 1/2W R482 1-260-089-11 CARBON 150 5% 1/2W R483 1-260-089-11 CARBON 150 5% 1/2W R484 1-260-089-11 CARBON 150 5% 1/2W R501 1-249-413-11 CARBON 470 5% 1/4W R502 1-249-425-11 CARBON 4.7K 5% 1/4W R503 1-249-437-11 CARBON 47K 5% 1/4W R504 1-249-437-11 CARBON 47K 5% 1/4W R505 1-249-429-11 CARBON 10K 5% 1/4W R508 1-249-421-11 CARBON 2.2K 5% 1/4W R509 1-249-441-11 CARBON 100K 5% 1/4W R521 1-249-425-11 CARBON 4.7K 5% 1/4W R522 1-249-411-11 CARBON 330 5% 1/4W R523 1-249-421-11 CARBON 2.2K 5% 1/4W (GRX70: E2, MX, AR) R523 1-249-425-11 CARBON 4.7K 5% 1/4W (GRX70: TH, AUS/GRX70J: EA3) R524 1-247-843-11 CARBON 3.3K 5% 1/4W (GRX70J: EA3) R524 1-249-411-11 CARBON 330 5% 1/4W (GRX70: TH, AUS) R524 1-249-425-11 CARBON 4.7K 5% 1/4W (GRX70: E2, MX, AR) R527 1-249-429-11 CARBON 10K 5% 1/4W R536 1-249-429-11 CARBON 10K 5% 1/4W R550 1-247-843-11 CARBON 3.3K 5% 1/4W R551 1-249-429-11 CARBON 10K 5% 1/4W R567 1-247-807-31 CARBON 100 5% 1/4W R568 1-249-429-11 CARBON 10K 5% 1/4W R569 1-249-429-11 CARBON 10K 5% 1/4W R570 1-249-429-11 CARBON 10K 5% 1/4W R571 1-249-429-11 CARBON 10K 5% 1/4W R577 1-249-429-11 CARBON 10K 5% 1/4W R610 1-247-891-00 CARBON 330K 5% 1/4W R617 1-249-429-11 CARBON 10K 5% 1/4W R618 1-247-807-31 CARBON 100 5% 1/4W R619 1-247-807-31 CARBON 100 5% 1/4W R622 1-249-425-11 CARBON 4.7K 5% 1/4W R626 1-247-807-31 CARBON 100 5% 1/4W R627 1-247-807-31 CARBON 100 5% 1/4W R629 1-247-807-31 CARBON 100 5% 1/4W R630 1-247-807-31 CARBON 100 5% 1/4W R632 1-247-807-31 CARBON 100 5% 1/4W R633 1-247-807-31 CARBON 100 5% 1/4W R635 1-249-413-11 CARBON 470 5% 1/4W R636 1-247-807-31 CARBON 100 5% 1/4W R637 1-249-417-11 CARBON 1K 5% 1/4W R639 1-247-807-31 CARBON 100 5% 1/4W R642 1-247-807-31 CARBON 100 5% 1/4W R643 1-247-807-31 CARBON 100 5% 1/4W R649 1-247-807-31 CARBON 100 5% 1/4W R650 1-247-807-31 CARBON 100 5% 1/4W R651 1-247-807-31 CARBON 100 5% 1/4W R652 1-247-807-31 CARBON 100 5% 1/4W R653 1-247-807-31 CARBON 100 5% 1/4W R654 1-247-807-31 CARBON 100 5% 1/4W R655 1-247-807-31 CARBON 100 5% 1/4W R656 1-247-807-31 CARBON 100 5% 1/4W R657 1-247-807-31 CARBON 100 5% 1/4W R658 1-249-417-11 CARBON 1K 5% 1/4W R659 1-247-807-31 CARBON 100 5% 1/4W R660 1-247-807-31 CARBON 100 5% 1/4W R661 1-247-807-31 CARBON 100 5% 1/4W R663 1-247-807-31 CARBON 100 5% 1/4W R665 1-247-807-31 CARBON 100 5% 1/4W R666 1-247-807-31 CARBON 100 5% 1/4W R667 1-247-807-31 CARBON 100 5% 1/4W R668 1-247-807-31 CARBON 100 5% 1/4W R669 1-247-807-31 CARBON 100 5% 1/4W R670 1-247-807-31 CARBON 100 5% 1/4W R671 1-247-807-31 CARBON 100 5% 1/4W R686 1-247-807-31 CARBON 100 5% 1/4W R687 1-247-807-31 CARBON 100 5% 1/4W R688 1-247-807-31 CARBON 100 5% 1/4W R689 1-247-807-31 CARBON 100 5% 1/4W R690 1-247-807-31 CARBON 100 5% 1/4W R691 1-247-807-31 CARBON 100 5% 1/4W R801 1-249-417-11 CARBON 1K 5% 1/4W R802 1-249-438-11 CARBON 56K 5% 1/4W R803 1-247-822-11 CARBON 430 5% 1/4W (GRX70J) R803 1-249-411-11 CARBON 330 5% 1/4W (GRX70) R803 1-249-414-11 CARBON 560 5% 1/4W (RXD80) R804 1-249-438-11 CARBON 56K 5% 1/4W R805 1-249-417-11 CARBON 1K 5% 1/4W R806 1-249-431-11 CARBON 15K 5% 1/4W R807 1-249-441-11 CARBON 100K 5% 1/4W !R808 1-220-893-11 METAL 0.22 10% 5W R809 1-260-076-11 CARBON 10 5% 1/2W R810 1-260-105-11 CARBON 3.3K 5% 1/2W !R811 1-212-881-11 FUSIBLE 100 5% 1/4W F !R812 1-202-972-61 FUSIBLE 1 5% 1/4W F R813 1-249-435-11 CARBON 33K 5% 1/4W R814 1-249-421-11 CARBON 2.2K 5% 1/4W R815 1-249-433-11 CARBON 22K 5% 1/4W R816 1-249-429-11 CARBON 10K 5% 1/4W R817 1-249-421-11 CARBON 2.2K 5% 1/4W R818 1-249-435-11 CARBON 33K 5% 1/4W R819 1-249-439-11 CARBON 68K 5% 1/4W R831 1-249-441-11 CARBON 100K 5% 1/4W R832 1-249-441-11 CARBON 100K 5% 1/4W R833 1-249-436-11 CARBON 39K 5% 1/4W R842 1-249-441-11 CARBON 100K 5% 1/4W R851 1-249-417-11 CARBON 1K 5% 1/4W R852 1-249-438-11 CARBON 56K 5% 1/4W R853 1-247-822-11 CARBON 430 5% 1/4W (GRX70J) R853 1-249-411-11 CARBON 330 5% 1/4W (GRX70) R853 1-249-414-11 CARBON 560 5% 1/4W (RXD80) R854 1-249-438-11 CARBON 56K 5% 1/4W R855 1-249-417-11 CARBON 1K 5% 1/4W R856 1-249-431-11 CARBON 15K 5% 1/4W The components identified by mark ! or dotted line with mark ! are critical for safety. Replace only with part num- ber specified. Les composants identifiés par une marque ! sont critiques pour la sécurité. Ne les remplacer que par une pièce portant le neméro spécifié. MAIN www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 89 – Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark R857 1-249-441-11 CARBON 100K 5% 1/4W !R858 1-220-893-11 METAL 0.22 10% 5W R859 1-260-076-11 CARBON 10 5% 1/2W R860 1-260-105-11 CARBON 3.3K 5% 1/2W !R861 1-212-881-11 FUSIBLE 100 5% 1/4W F R881 1-249-435-11 CARBON 33K 5% 1/4W R882 1-249-435-11 CARBON 33K 5% 1/4W R892 1-249-441-11 CARBON 100K 5% 1/4W R901 1-247-843-11 CARBON 3.3K 5% 1/4W R902 1-249-415-11 CARBON 680 5% 1/4W R903 1-249-419-11 CARBON 1.5K 5% 1/4W R904 1-249-414-11 CARBON 560 5% 1/4W R905 1-249-425-11 CARBON 4.7K 5% 1/4W R906 1-247-843-11 CARBON 3.3K 5% 1/4W R907 1-249-415-11 CARBON 680 5% 1/4W R908 1-249-429-11 CARBON 10K 5% 1/4W R909 1-249-430-11 CARBON 12K 5% 1/4W R911 1-249-409-11 CARBON 220 5% 1/4W R920 1-249-383-11 CARBON 1.5 5% 1/6W R921 1-249-383-11 CARBON 1.5 5% 1/6W R931 1-249-429-11 CARBON 10K 5% 1/4W < VARIABLE RESISTOR > RV301 1-238-600-11 RES, ADJ, CARBON 10K RV351 1-238-600-11 RES, ADJ, CARBON 10K < RELAY > RY401 1-755-168-11 RELAY < THERMISTOR > TH831 1-807-796-11 THERMISTOR < TERMINAL > TM401 1-537-240-31 TERMINAL BOARD (CHECKER PIN) (SPEAKER) TM402 1-537-240-31 TERMINAL BOARD (CHECKER PIN) (SURROUND SPEAKER) (GRX70/GRX70J) < VIBRATOR > X601 1-567-098-41 VIBRATOR, CRYSTAL (32.768kHz) X613 1-781-107-21 VIBRATOR, SERAMIC (16MHz) ************************************************************ * 1-658-578-11 MOTOR (SLIDE) BOARD ******************* < CAPACITOR > C801 1-162-306-11 CERAMIC 0.01uF 20% 16V C804 1-162-306-11 CERAMIC 0.01uF 20% 16V C805 1-126-964-11 ELECT 10uF 20% 50V < CONNECTOR > * CN801 1-568-947-11 PIN, CONNECTOR 9P < DIODE > D801 8-719-921-48 DIODE MTZJ-T-72-5.6C D804 8-719-911-19 DIODE 1SS119 D805 8-719-911-19 DIODE 1SS119 < IC > IC801 8-759-274-09 IC BA6286N < RESISTOR > R801 1-249-401-11 CARBON 47 5% 1/4W < SWITCH > S801 1-762-527-11 SWITCH, ROTARY (OPEN/CLOSE DET) ************************************************************ * 1-658-577-11 MOTOR (TURN) BOARD ******************* < CAPACITOR > C701 1-162-306-11 CERAMIC 0.01uF 20% 16V C702 1-126-964-11 ELECT 10uF 20% 50V C705 1-162-306-11 CERAMIC 0.01uF 20% 16V < CONNECTOR > CN703 1-750-413-11 CONNECTOR, FFC/FPC 8P CN703 1-785-550-11 CONNECTOR, FFC/FPC 8P CN704 1-506-469-11 PIN, CONNECTOR 4P < DIODE > D701 8-719-983-66 DIODE MTZJ-T-72-3.6B < IC > IC701 8-759-633-65 IC M54641L < RESISTOR > R706 1-249-411-11 CARBON 330 5% 1/4W R707 1-249-401-11 CARBON 47 5% 1/4W ************************************************************ * A-4417-808-A PANEL BOARD, COMPLETE (GRX70/RXD80) A-4419-985-A PANEL BOARD, COMPLETE (GRX70J: E3) A-4426-002-A PANEL BOARD, COMPLETE (GRX70J: EA3) ********************** * 4-214-439-11 HOLDER, FL TUBE < CAPACITOR > C601 1-124-589-11 ELECT 47uF 20% 16V C602 1-126-163-11 ELECT 4.7uF 20% 50V C603 1-162-306-11 CERAMIC 0.01uF 20% 16V C604 1-164-159-11 CERAMIC 0.1uF 50V C606 1-126-160-11 ELECT 1uF 20% 50V C607 1-126-160-11 ELECT 1uF 20% 50V C610 1-124-589-11 ELECT 47uF 20% 16V C611 1-162-306-11 CERAMIC 0.01uF 20% 16V C612 1-162-306-11 CERAMIC 0.01uF 20% 16V C614 1-162-306-11 CERAMIC 0.01uF 20% 16V C615 1-162-306-11 CERAMIC 0.01uF 20% 16V C616 1-126-157-11 ELECT 10uF 20% 16V C617 1-162-303-11 CERAMIC 0.0033uF 30% 16V MAIN MOTOR (SLIDE) MOTOR (TURN) PANEL The components identified by mark ! or dotted line with mark ! are critical for safety. Replace only with part num- ber specified. Les composants identifiés par une marque ! sont critiques pour la sécurité. Ne les remplacer que par une pièce portant le neméro spécifié. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 90 – Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark C618 1-126-157-11 ELECT 10uF 20% 16V C619 1-126-157-11 ELECT 10uF 20% 16V C620 1-126-163-11 ELECT 4.7uF 20% 50V C625 1-126-157-11 ELECT 10uF 20% 16V C627 1-162-306-11 CERAMIC 0.01uF 20% 16V C628 1-126-157-11 ELECT 10uF 20% 16V C630 1-162-306-11 CERAMIC 0.01uF 20% 16V C651 1-162-282-31 CERAMIC 100PF 10% 50V C652 1-162-282-31 CERAMIC 100PF 10% 50V C653 1-162-282-31 CERAMIC 100PF 10% 50V C654 1-162-282-31 CERAMIC 100PF 10% 50V C655 1-162-282-31 CERAMIC 100PF 10% 50V C656 1-162-282-31 CERAMIC 100PF 10% 50V C657 1-162-282-31 CERAMIC 100PF 10% 50V C658 1-162-282-31 CERAMIC 100PF 10% 50V C659 1-162-282-31 CERAMIC 100PF 10% 50V C660 1-162-282-31 CERAMIC 100PF 10% 50V C661 1-162-282-31 CERAMIC 100PF 10% 50V C662 1-162-282-31 CERAMIC 100PF 10% 50V C663 1-162-282-31 CERAMIC 100PF 10% 50V C664 1-162-282-31 CERAMIC 100PF 10% 50V C665 1-162-282-31 CERAMIC 100PF 10% 50V C666 1-162-282-31 CERAMIC 100PF 10% 50V C667 1-162-282-31 CERAMIC 100PF 10% 50V C668 1-162-282-31 CERAMIC 100PF 10% 50V C701 1-162-294-31 CERAMIC 0.001uF 10% 50V C702 1-162-294-31 CERAMIC 0.001uF 10% 50V C703 1-164-159-11 CERAMIC 0.1uF 50V C711 1-162-294-31 CERAMIC 0.001uF 10% 50V (GRX70J: EA3) C712 1-162-305-11 CERAMIC 0.0068uF 30% 16V (GRX70J: EA3) C713 1-126-160-11 ELECT 1uF 20% 50V (GRX70J: EA3) C714 1-136-495-11 FILM 0.068uF 5% 50V (GRX70J: EA3) C715 1-124-465-00 ELECT 0.47uF 20% 50V (GRX70J: EA3) C716 1-124-465-00 ELECT 0.47uF 20% 50V (GRX70J: EA3) C717 1-136-167-00 FILM 0.15uF 5% 50V (GRX70J: EA3) C718 1-162-294-31 CERAMIC 0.001uF 10% 50V (GRX70J: EA3) C719 1-126-160-11 ELECT 1uF 20% 50V (GRX70J: EA3) C720 1-161-494-00 CERAMIC 0.022uF 25V (GRX70J: EA3) C721 1-162-305-11 CERAMIC 0.0068uF 30% 16V (GRX70J: EA3) C722 1-136-495-11 FILM 0.068uF 5% 50V (GRX70J: EA3) C723 1-124-589-11 ELECT 47uF 20% 16V (GRX70J: EA3) C724 1-136-165-00 FILM 0.1uF 5% 50V (GRX70J: EA3) C725 1-124-589-11 ELECT 47uF 20% 16V (GRX70J: EA3) C731 1-162-306-11 CERAMIC 0.01uF 20% 16V C732 1-124-257-00 ELECT 2.2uF 20% 50V C733 1-162-294-31 CERAMIC 0.001uF 10% 50V C734 1-162-215-31 CERAMIC 47PF 5% 50V C735 1-124-261-00 ELECT 10uF 20% 50V C736 1-162-290-31 CERAMIC 470PF 10% 50V C737 1-124-463-00 ELECT 0.1uF 20% 50V C738 1-124-257-00 ELECT 2.2uF 20% 50V (GRX70J: EA3) C739 1-162-215-31 CERAMIC 47PF 5% 50V C741 1-124-261-00 ELECT 10uF 20% 50V C742 1-162-282-31 CERAMIC 100PF 10% 50V C743 1-124-257-00 ELECT 2.2uF 20% 50V C747 1-164-159-11 CERAMIC 0.1uF 50V < CONNECTOR > CN601 1-784-745-11 CONNECTOR, FFC 23P < DIODE > D610 8-719-050-84 DIODE RB441Q-40T-72 D611 8-719-073-47 LED SML72923C-TP15 (REC PAUSE/START) D612 8-719-056-13 LED SML79423C-TP15 (^ CD) D613 8-719-058-03 LED SEL5423E-TP15 (( TAPE B) D614 8-719-058-03 LED SEL5423E-TP15 (9 TAPE B) D615 8-719-058-03 LED SEL5423E-TP15 (( TAPE A) D616 8-719-058-03 LED SEL5423E-TP15 (9 TAPE A) D619 8-719-057-97 LED SEL5923A-TP15 (SYNC BASS L) D620 8-719-057-97 LED SEL5923A-TP15 (SYNC BASS H) D621 8-719-057-97 LED SEL5923A-TP15 (SYNC EQ) D622 8-719-063-93 LED SLR325VC-N-T32 (EFFECT) D624 8-719-063-93 LED SLR325VC-N-T32 (NON-STOP) D627 8-719-057-97 LED SEL5923A-TP15 (GROOVE) D628 8-719-063-93 LED SLR325VC-N-T32 (ENTER/NEXT) D629 8-719-063-93 LED SLR325VC-N-T32 (JOG DIAL) D630 8-719-057-97 LED SEL5923A-TP15 (- )) D631 8-719-057-97 LED SEL5923A-TP15 (+ 0) D632 8-719-063-93 LED SLR325VC-N-T32 (TIMER SELECT) D701 8-719-109-85 DIODE RD5.1ES-B2 (GRX70J: EA3) < EARTH TERMINAL > * EP601 1-537-738-21 TERMINAL, EARTH < FERRITE BEAD > FB601 1-412-473-21 FERRITE 0uH FB602 1-412-473-21 FERRITE 0uH < FLUORESCENT INDICATOR TUBE > FL601 1-517-831-11 INDICATOR TUBE, FLUORESCENT < IC > IC601 8-759-589-13 IC TMP88CS76F-6004 IC602 8-749-011-05 IC GP1U28X IC603 8-759-083-77 IC BA3830F IC604 8-759-342-19 IC NJU3716M-T2 IC711 8-759-496-40 IC M65850FP (GRX70J: EA3) IC712 8-759-636-55 IC M5218AFP PANEL www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 91 – Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark < JACK > J701 1-785-569-11 JACK (SMALL TYPE) (PHONES) J711 1-785-569-11 JACK (SMALL TYPE) (MIX MIC) < COIL > L601 1-410-509-11 INDUCTOR 10uH L602 1-410-517-11 INDUCTOR 47uH < TRANSISTOR > Q601 8-729-118-00 TRANSISTOR 2SB1116-L Q602 8-729-118-00 TRANSISTOR 2SB1116-L Q603 8-729-119-78 TRANSISTOR 2SC403SP-51 Q604 8-729-422-57 TRANSISTOR UN4111 Q605 8-729-422-57 TRANSISTOR UN4111 Q606 8-729-900-80 TRANSISTOR DTC114ES Q607 8-729-900-74 TRANSISTOR DTC143TS Q608 8-729-900-74 TRANSISTOR DTC143TS Q609 8-729-900-74 TRANSISTOR DTC143TS Q610 8-729-900-74 TRANSISTOR DTC143TS Q611 8-729-900-74 TRANSISTOR DTC143TS Q612 8-729-900-74 TRANSISTOR DTC143TS Q613 8-729-900-74 TRANSISTOR DTC143TS < RESISTOR > R600 1-247-903-00 CARBON 1M 5% 1/4W R601 1-247-807-31 CARBON 100 5% 1/4W R602 1-249-429-11 CARBON 10K 5% 1/4W R603 1-247-807-31 CARBON 100 5% 1/4W R604 1-247-807-31 CARBON 100 5% 1/4W R605 1-249-429-11 CARBON 10K 5% 1/4W R606 1-249-401-11 CARBON 47 5% 1/4W R607 1-247-893-11 CARBON 390K 5% 1/4W R608 1-247-893-11 CARBON 390K 5% 1/4W R609 1-249-441-11 CARBON 100K 5% 1/4W R610 1-249-429-11 CARBON 10K 5% 1/4W R611 1-249-441-11 CARBON 100K 5% 1/4W R612 1-249-401-11 CARBON 47 5% 1/4W R613 1-249-435-11 CARBON 33K 5% 1/4W R614 1-247-895-00 CARBON 470K 5% 1/4W R615 1-249-429-11 CARBON 10K 5% 1/4W R616 1-249-441-11 CARBON 100K 5% 1/4W R617 1-249-441-11 CARBON 100K 5% 1/4W R618 1-249-441-11 CARBON 100K 5% 1/4W R619 1-249-441-11 CARBON 100K 5% 1/4W R620 1-249-441-11 CARBON 100K 5% 1/4W R621 1-249-429-11 CARBON 10K 5% 1/4W R622 1-249-410-11 CARBON 270 5% 1/4W R623 1-249-411-11 CARBON 330 5% 1/4W R624 1-249-413-11 CARBON 470 5% 1/4W R625 1-249-414-11 CARBON 560 5% 1/4W R626 1-249-415-11 CARBON 680 5% 1/4W R627 1-249-417-11 CARBON 1K 5% 1/4W R628 1-249-418-11 CARBON 1.2K 5% 1/4W R629 1-249-420-11 CARBON 1.8K 5% 1/4W R630 1-249-422-11 CARBON 2.7K 5% 1/4W R631 1-247-843-11 CARBON 3.3K 5% 1/4W R632 1-249-425-11 CARBON 4.7K 5% 1/4W R633 1-249-427-11 CARBON 6.8K 5% 1/4W R634 1-249-429-11 CARBON 10K 5% 1/4W R635 1-249-431-11 CARBON 15K 5% 1/4W R636 1-249-429-11 CARBON 10K 5% 1/4W R637 1-249-410-11 CARBON 270 5% 1/4W R638 1-249-411-11 CARBON 330 5% 1/4W R639 1-249-413-11 CARBON 470 5% 1/4W R640 1-249-414-11 CARBON 560 5% 1/4W R641 1-249-415-11 CARBON 680 5% 1/4W R642 1-249-417-11 CARBON 1K 5% 1/4W R650 1-249-429-11 CARBON 10K 5% 1/4W R651 1-249-410-11 CARBON 270 5% 1/4W R652 1-249-411-11 CARBON 330 5% 1/4W R653 1-249-413-11 CARBON 470 5% 1/4W R654 1-249-414-11 CARBON 560 5% 1/4W R655 1-249-415-11 CARBON 680 5% 1/4W R656 1-249-429-11 CARBON 10K 5% 1/4W R657 1-249-410-11 CARBON 270 5% 1/4W R658 1-249-411-11 CARBON 330 5% 1/4W R659 1-249-413-11 CARBON 470 5% 1/4W R660 1-249-414-11 CARBON 560 5% 1/4W R661 1-249-415-11 CARBON 680 5% 1/4W R662 1-249-417-11 CARBON 1K 5% 1/4W R663 1-249-418-11 CARBON 1.2K 5% 1/4W R664 1-249-420-11 CARBON 1.8K 5% 1/4W R665 1-249-422-11 CARBON 2.7K 5% 1/4W R666 1-249-417-11 CARBON 1K 5% 1/4W R667 1-249-417-11 CARBON 1K 5% 1/4W R668 1-249-441-11 CARBON 100K 5% 1/4W R669 1-249-441-11 CARBON 100K 5% 1/4W R670 1-249-414-11 CARBON 560 5% 1/4W R671 1-249-437-11 CARBON 47K 5% 1/4W R672 1-249-417-11 CARBON 1K 5% 1/4W R673 1-249-437-11 CARBON 47K 5% 1/4W R674 1-249-417-11 CARBON 1K 5% 1/4W R675 1-249-437-11 CARBON 47K 5% 1/4W R676 1-249-429-11 CARBON 10K 5% 1/4W R678 1-249-407-11 CARBON 150 5% 1/4W R679 1-249-407-11 CARBON 150 5% 1/4W R680 1-247-804-11 CARBON 75 5% 1/4W R681 1-249-407-11 CARBON 150 5% 1/4W R682 1-247-804-11 CARBON 75 5% 1/4W R683 1-247-804-11 CARBON 75 5% 1/4W R684 1-247-804-11 CARBON 75 5% 1/4W R685 1-247-804-11 CARBON 75 5% 1/4W R688 1-249-402-11 CARBON 56 5% 1/4W R689 1-249-402-11 CARBON 56 5% 1/4W R690 1-249-402-11 CARBON 56 5% 1/4W R691 1-249-407-11 CARBON 150 5% 1/4W R693 1-249-407-11 CARBON 150 5% 1/4W R696 1-249-402-11 CARBON 56 5% 1/4W R697 1-249-407-11 CARBON 150 5% 1/4W R698 1-249-407-11 CARBON 150 5% 1/4W R699 1-247-807-31 CARBON 100 5% 1/4W R700 1-247-807-31 CARBON 100 5% 1/4W R701 1-249-429-11 CARBON 10K 5% 1/4W R702 1-249-429-11 CARBON 10K 5% 1/4W PANEL www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 92 – Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark R703 1-249-429-11 CARBON 10K 5% 1/4W R704 1-249-429-11 CARBON 10K 5% 1/4W R705 1-249-429-11 CARBON 10K 5% 1/4W R710 1-249-401-11 CARBON 47 5% 1/4W (GRX70J: EA3) R711 1-249-433-11 CARBON 22K 5% 1/4W (GRX70J: EA3) R712 1-249-433-11 CARBON 22K 5% 1/4W (GRX70J: EA3) R713 1-249-433-11 CARBON 22K 5% 1/4W (GRX70J: EA3) R714 1-249-437-11 CARBON 47K 5% 1/4W (GRX70J: EA3) R715 1-249-433-11 CARBON 22K 5% 1/4W (GRX70J: EA3) R716 1-249-431-11 CARBON 15K 5% 1/4W (GRX70J: EA3) R717 1-249-433-11 CARBON 22K 5% 1/4W (GRX70J: EA3) R718 1-249-433-11 CARBON 22K 5% 1/4W (GRX70J: EA3) R719 1-247-881-00 CARBON 120K 5% 1/4W (GRX70J: EA3) R721 1-249-429-11 CARBON 10K 5% 1/4W R722 1-249-417-11 CARBON 1K 5% 1/4W R723 1-249-441-11 CARBON 100K 5% 1/4W R724 1-249-417-11 CARBON 1K 5% 1/4W R725 1-249-433-11 CARBON 22K 5% 1/4W R726 1-249-429-11 CARBON 10K 5% 1/4W R727 1-249-431-11 CARBON 15K 5% 1/4W (GRX70J: EA3) R728 1-247-885-00 CARBON 180K 5% 1/4W R729 1-247-807-31 CARBON 100 5% 1/4W R731 1-249-440-11 CARBON 82K 5% 1/4W R732 1-249-437-11 CARBON 47K 5% 1/4W R733 1-249-440-11 CARBON 82K 5% 1/4W R734 1-249-417-11 CARBON 1K 5% 1/4W R735 1-249-420-11 CARBON 1.8K 5% 1/4W R741 1-249-421-11 CARBON 2.2K 5% 1/4W R742 1-249-421-11 CARBON 2.2K 5% 1/4W R743 1-249-421-11 CARBON 2.2K 5% 1/4W < VARIABLE RESISTOR > RV711 1-225-739-11 RES, VAR 50K (ECHO LEVEL) (GRX70J: EA3) RV712 1-225-739-11 RES, VAR 50K (MIC LEVEL) < SWITCH > S601 1-473-534-11 ENCODER, ROTARY (JOG DIAL) S602 1-473-392-11 ENCODER, ROTARY (VOLUME) S611 1-762-875-21 SWITCH, KEYBOARD (SYNC BASS) S612 1-762-875-21 SWITCH, KEYBOARD (SYNC EQ) S613 1-762-875-21 SWITCH, KEYBOARD (KARAOKE PON/MPX) S614 1-762-875-21 SWITCH, KEYBOARD (NON-STOP) S615 1-762-875-21 SWITCH, KEYBOARD (SURROUND) S616 1-762-875-21 SWITCH, KEYBOARD (DBFB) S617 1-762-875-21 SWITCH, KEYBOARD (ENTER/NEXT) S618 1-762-875-21 SWITCH, KEYBOARD (+ )) S619 1-762-875-21 SWITCH, KEYBOARD (- 0) S620 1-762-875-21 SWITCH, KEYBOARD (GROOVE) S621 1-762-875-21 SWITCH, KEYBOARD (FLASH) S622 1-762-875-21 SWITCH, KEYBOARD (REPEAT STEREO/MONO) S623 1-762-875-21 SWITCH, KEYBOARD (PLAY MODE, DOLBY NR) S624 1-762-875-21 SWITCH, KEYBOARD (EDIT, DIRECTION, TUNER MEMORY) S625 1-762-875-21 SWITCH, KEYBOARD (REC PAUSE/START) S626 1-762-875-21 SWITCH, KEYBOARD (HI-DUB) S627 1-762-875-21 SWITCH, KEYBOARD (CD SYNC) S628 1-762-875-21 SWITCH, KEYBOARD (LOOP) S629 1-762-875-21 SWITCH, KEYBOARD (DISPLAY) S630 1-762-875-21 SWITCH, KEYBOARD (SPECTRUM ANALYZER) S638 1-762-875-21 SWITCH, KEYBOARD (TIMER SELECT) S639 1-762-875-21 SWITCH, KEYBOARD (P FILE MEMORY) S640 1-762-875-21 SWITCH, KEYBOARD (GEQ CONTROL) S641 1-762-875-21 SWITCH, KEYBOARD (FILE SELECT) S642 1-762-875-21 SWITCH, KEYBOARD (EFFECT) S643 1-762-875-21 SWITCH, KEYBOARD (TUNER BAND) S644 1-762-875-21 SWITCH, KEYBOARD (^ CD) S645 1-762-875-21 SWITCH, KEYBOARD (p) S646 1-762-875-21 SWITCH, KEYBOARD (( TAPE B) S647 1-762-875-21 SWITCH, KEYBOARD (9 TAPE B) S648 1-762-875-21 SWITCH, KEYBOARD (( TAPE A) S649 1-762-875-21 SWITCH, KEYBOARD (9 TAPE A) S650 1-762-875-21 SWITCH, KEYBOARD (FUNCTION) S651 1-762-875-21 SWITCH, KEYBOARD (CLOCK TIMER SET) < VIBRATOR > X601 1-781-312-11 VIBRATOR, CERAMIC (12.5MHz) ************************************************************ * 1-658-576-11 SENSOR BOARD ************* < PHOTO INTERRUPTER > IC702 8-749-924-18 PHOTO INTERRUPTER RPI-1391 < PHOTO REFLECTOR > IC703 8-749-924-30 PHOTO REFLECTOR GP2S28 < RESISTOR > R701 1-249-416-11 CARBON 820 5% 1/4W R702 1-249-407-11 CARBON 150 5% 1/4W ************************************************************ * A-4417-729-A SUB TRANS BOARD, COMPLETE (RXD80) ************************** < CAPACITOR > C11 1-126-768-11 ELECT 2200uF 20% 16V C12 1-164-159-11 CERAMIC 0.1uF 50V C13 1-126-933-11 ELECT 100uF 20% 16V C14 1-126-968-11 ELECT 100uF 20% 50V C15 1-164-159-11 CERAMIC 0.1uF 50V C16 1-126-948-11 ELECT 100uF 20% 35V !C21 1-113-925-11 CERAMIC 0.01uF 20% 250V PANEL SENSOR SUB TRANS The components identified by mark ! or dotted line with mark ! are critical for safety. Replace only with part num- ber specified. Les composants identifiés par une marque ! sont critiques pour la sécurité. Ne les remplacer que par une pièce portant le neméro spécifié. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 93 – Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark < CONNECTOR > CN11 1-564-321-00 PIN, CONNECTOR 2P * CN12 1-564-321-21 PIN, CONNECTOR 2P CN13 1-785-333-11 PIN, CONNECTOR (LIGHT ANGLE) 7P < DIODE > D11 8-719-911-19 DIODE 1SS119 D12 8-719-210-21 DIODE 11EQS04 D13 8-719-210-21 DIODE 11EQS04 D14 8-719-210-21 DIODE 11EQS04 D15 8-719-210-21 DIODE 11EQS04 D16 8-719-911-19 DIODE 1SS119 D17 8-719-024-99 DIODE 11ES2-NTA2B D18 8-719-024-99 DIODE 11ES2-NTA2B D19 8-719-024-99 DIODE 11ES2-NTA2B D20 8-719-024-99 DIODE 11ES2-NTA2B D21 8-719-986-60 DIODE HZS27-3LTA D22 8-719-109-63 DIODE RD3.0ESB2 D23 8-719-911-19 DIODE 1SS119 < IC > IC11 8-759-450-47 IC BA05T < TRANSISTOR > Q11 8-729-119-78 TRANSISTOR 2SC403SP-51 Q12 8-729-040-19 TRANSISTOR RT1N137L-TP Q13 8-729-118-01 TRANSISTOR 2SB1116 Q14 8-729-040-19 TRANSISTOR RT1N137L-TP Q15 8-729-040-19 TRANSISTOR RT1N137L-TP Q16 8-729-900-63 TRANSISTOR DTA124ES Q17 8-729-900-63 TRANSISTOR DTA124ES < RESISTOR > R11 1-249-429-11 CARBON 10K 5% 1/4W R12 1-249-441-11 CARBON 100K 5% 1/4W R13 1-249-417-11 CARBON 1K 5% 1/4W R15 1-249-429-11 CARBON 10K 5% 1/4W R16 1-247-807-31 CARBON 100 5% 1/4W R17 1-247-807-31 CARBON 100 5% 1/4W R18 1-247-807-31 CARBON 100 5% 1/4W R19 1-249-427-11 CARBON 6.8K 5% 1/4W R20 1-249-429-11 CARBON 10K 5% 1/4W R23 1-249-427-11 CARBON 6.8K 5% 1/4W < RELAY > !RY11 1-755-276-11 RELAY, POWER < TRANSFORMER > !T11 1-433-587-11 TRANSFORMER, POWER ************************************************************ * 1-672-369-11 TRANS BOARD ************************ 1-533-217-31 HOLDER, FUSE < CAPACITOR > !C952 1-162-306-11 CERAMIC 0.01uF 20% 16V (GRX70J) C971 1-128-563-11 ELECT 100uF 20% 100V (GRX70/GRX70J) C972 1-126-960-11 ELECT 1uF 20% 50V (GRX70/GRX70J) C973 1-126-948-11 ELECT 100uF 20% 35V (GRX70/GRX70J) < CONNECTOR > CN951 1-564-321-00 PIN, CONNECTOR 2P (GRX70/GRX70J) * CN952 1-564-527-11 PLUG, CONNECTOR 12P (GRX70/GRX70J) * CN952 1-564-524-11 PLUG, CONNECTOR 9P (RXD80) CN953 1-785-329-11 PIN, CONNECTOR (LIGHT ANGLE) 3P (GRX70/GRX70J) < DIODE > D971 8-719-024-99 DIODE 11ES2-NTA2B (GRX70/GRX70J) D972 8-719-986-60 DIODE HZS27-3LTA (GRX70/GRX70J) D973 8-719-109-63 DIODE RD3.0ESB2 (GRX70/GRX70J) < FUSE > !F951 1-532-506-31 FUSE T6.3AL/250V (GRX70: E2, E3, SP, TW, AR/GRX70J) !F951 1-533-310-11 FUSE, GLASS TUBE 6.3A/125V (RXD80) !F961 1-532-505-31 FUSE T5AL/250V (GRX70/GRX70J) !F962 1-532-505-31 FUSE T5AL/250V (GRX70/GRX70J) !F963 1-532-506-31 FUSE T6.3AL/250V (GRX70/GRX70J) !F964 1-532-506-31 FUSE T6.3AL/250V (GRX70/GRX70J) < TRANSISTOR > Q971 8-729-048-52 TRANSISTOR 2SA1932 (TP) (GRX70/GRX70J) < RESISTOR > !R951 1-219-120-11 FUSIBLE 0.15 5% 1/4W F (RXD80) !R951 1-219-122-91 FUSIBLE 0.33 5% 1/4W F (GRX70/GRX70J) !R952 1-219-122-91 FUSIBLE 0.33 5% 1/4W F (RXD80) !R952 1-219-120-11 FUSIBLE 0.15 5% 1/4W F (GRX70/GRX70J) !R953 1-219-119-81 FUSIBLE 0.1 5% 1/4W F !R961 1-202-725-00 SOLID 3.3M 10% 1/2W (RXD80) !R971 1-216-456-00 METAL OXIDE 820 5% 2W F (GRX70/GRX70J) R972 1-249-429-11 CARBON 10K 5% 1/4W (GRX70/GRX70J) R973 1-249-429-11 CARBON 10K 5% 1/4W (GRX70/GRX70J) R974 1-247-807-31 CARBON 100 5% 1/4W (GRX70/GRX70J) R975 1-247-807-31 CARBON 100 5% 1/4W (GRX70/GRX70J) The components identified by mark ! or dotted line with mark ! are critical for safety. Replace only with part num- ber specified. Les composants identifiés par une marque ! sont critiques pour la sécurité. Ne les remplacer que par une pièce portant le neméro spécifié. SUB TRANS TRANS www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 94 – Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark < SWITCH > !S951 1-771-291-11 SWITCH, POWER (VOLTAGE SELECTOR) (GRX70: E2, E3, SP, TW, AR/GRX70J) < TRANSFORMER > !T951 1-433-561-11 TRANSFORMER, POWER (GRX70/GRX70J) !T951 1-433-562-21 TRANSFORMER, POWER (RXD80) ************************************************************ MISCELLANEOUS ************** 64 1-773-188-11 WIRE (FLAT TYPE) (23 CORE) 104 1-773-042-11 WIRE (FLAT TYPE) (17 CORE) (14cm) (GRX70: E3, TW, AR, AUS/RXD80) 104 1-773-043-11 WIRE (FLAT TYPE) (17 CORE) (15cm) (GRX70: E2, SP, TH, MX/GRX70J) 105 1-773-024-11 WIRE (FLAT TYPE) (15 CORE) (32cm) 106 1-783-570-11 WIRE (FLAT TYPE) (19 CORE) 109 1-769-977-11 WIRE (FLAT TYPE) (13 CORE) (GRX70: E2, TH, MX, AR, AUS/ RXD80) 109 1-773-009-11 WIRE (FLAT TYPE) (15 CORE) (15cm) (GRX70: E3, SP, TW/GRX70J) 110 1-233-544-14 TUNER PACK (RXD80) 110 1-233-545-11 TUNER (FM/AM) (GRX70: TH, AUS) 110 1-233-545-14 TUNER PACK (GRX70: MX, AR) 110 1-233-546-11 TUNER (FM/MW/SW) (GRX70: E3, SP, TW/ GRX70J) 110 1-693-453-11 TUNER (FM/AM) (GRX70: E2) !111 1-575-651-11 CORD, POWER (GRX70: SP, TW/GRX70J: EA3) !111 1-575-653-11 CORD, POWER (GRX70: E2, E3, TH, MX/ GRX70J: E3) !111 1-690-608-11 CORD, POWER (GRX70: AUS) !111 1-690-609-21 CORD, POWER (RXD80: CND) !111 1-783-941-21 CORD, POWER (GRX70: AR) !112 1-569-007-11 ADAPTOR, CONVERSION 2P (GRX70: E3/GRX70J: E3) !112 1-569-008-21 ADAPTOR, CONVERSION 2P (GRX70: SP, TW/GRX70J: EA3) 257 1-452-925-21 MAGNET ASSY 258 1-776-042-11 WIRE (FLAT TYPE) (8 CORE) !301 8-820-020-02 OPTICAL PICK-UP KSS-213D/Q-NP 302 1-769-069-11 WIRE (FLAT TYPE) (16 CORE) HP101 A-2056-681-A DECK (A) ASSY, HEAD HRPE101A-2056-682-A DECK (B) ASSY, HEAD M1 A-2004-628-A MOTOR ASSY, CAPSTAN M101 X-4917-523-4 MOTOR ASSY (SPINDLE) M102 X-4917-504-1 MOTOR ASSY (SLED) M501 1-698-792-11 FAN, DC M701 A-4672-004-A MOTOR ASSY (DISC TRAY TURN) M801 A-4672-004-A MOTOR ASSY (DISC TRAY SLIDE) S811 1-473-335-11 ENCODER, ROTARY (BU, TRAY ADDRESS DET) !T11 1-433-587-11 TRANSFORMER, POWER (RXD80) !T951 1-433-561-11 TRANSFORMER, POWER (GRX70/GRX70J) !T951 1-433-562-21 TRANSFORMER, POWER (RXD80) ************************************************************ The components identified by mark ! or dotted line with mark ! are critical for safety. Replace only with part num- ber specified. Les composants identifiés par une marque ! sont critiques pour la sécurité. Ne les remplacer que par une pièce portant le neméro spécifié. HCD-GRX70/GRX70J/RXD80 Sony Corporation Home A&V Products Company 9-928-843-11 99D057030-1 Printed in Singapore © 1999. 4 Published by Quality Assurance Dept. (Shinagawa) ************** HARDWARE LIST ************** #1 7-685-872-09 SCREW +BVTT 3X8 (S) #2 7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S #3 7-685-871-01 SCREW +BVTT 3X6 (S) #4 7-685-647-79 SCREW +BVTP 3X10 TYPE2 N-S #5 7-685-852-04 SCREW +BVTT 2X5 (S) #6 7-685-861-01 SCREW +BVTT 2.6X5 (S) #7 7-685-851-04 SCREW +BVTT 2X4 (S) #8 7-621-775-10 SCREW +B 2.6X4 #9 7-685-650-79 SCREW +BVTP 3X16 TYPE2 IT-3 #10 7-685-880-09 SCREW +BVTT 4X6 (S) #11 7-628-254-15 SCREW +PS 2.6X6 #12 7-628-254-50 SCREW +PS 2.6X16 TRANS www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com
