US Model Canadian Model HCD-RX33 E Model Australian Model HCD-GRX2 SERVICE MANUAL MINI Hi-Fi COMPONENT SYSTEM MICROFILM HCD-GRX2/RX33 is the tuner, deck, CD and amplifier section in MHC-GRX2/RX33. — Continued on next page — SPECIFICATIONS Model Name Using Similar Mechanism HCD-G101 CD Mechanism Type CX3 Base Unit Type KSM-213BCM Optical Pick-up Type KSS-213B/S-N Model Name Using Similar Mechanism HCD-G101 DECK-A TK20FX-SW943-800 DECK-B TK20FX-SW943-800 CD SECTION TAPE DECK SECTION Tape Transport Mechanism Type AUDIO POWER SPECIFICATIONS: (U.S.A. model only) POWER OUTPUT AND TOTAL HARMONIC DISTORTION: with 6 Ω loads both channels driven, from 70 – 20,000 Hz; rated 25 W per channel minimum RMS power, with no more than 0.9% total harmonic distortion from 250 mW to rated output. Amplifier section North American model Continuous RMS power output 35 W + 35 W (6 Ω at 1 kHz, 10% THD) Other models The following measured at AC 110, 220 V 60 Hz; DIN power output (Rated) 25 W + 25 W (6 Ω at 1 kHz, DIN) Continuous RMS power output (Reference) 30 W + 30W (6 Ω at 1 kHz, 10% THD) The following measured at AC 120, 240 V 60 Hz; DIN power output (Rated) 30 W + 30 W (6 Ω at 1 kHz, DIN) Continuous RMS power output (Reference) 35 W + 35W (6 Ω at 1 kHz, 10% THD) Peak music power output (Reference) 400 W Outputs PHONES (stereo phone jack) : accepts headphones of 8 Ω or more SPEAKER : accepts impedance of 6 to 16 Ω CD player section System Compact disc and digital audio system Laser Semiconductor laser (λ = 780 nm) Emission duration: continuous Laser output Max. 44.6 µW* *This output is the value measured at a distance of 200 mm from the objective lens surface on the Optical Pick-up Block with 7 mm aperture. Frequency response 20 Hz – 20 kHz (± 0.5 dB) Wavelength 780 – 790 nm Tape deck section Recording system 4 -track 2 -channel stereo Frequency response 60 – 13,000 Hz (± 3dB), using Sony TYPE Ι cassette Photo : HCD-GRX2 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com — 2 — CAUTION Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure. Notes on chip component replacement • Never reuse a disconnected chip component. • Notice that the minus side of a tantalum capacitor may be damaged by heat. Flexible Circuit Board Repairing • Keep the temperature of soldering iron around 270˚C during repairing. • Do not touch the soldering iron on the same conductor of the circuit board (within 3 times). • Be careful not to apply force on the conductor when soldering or unsoldering. Laser component in this product is capable of emitting radiation exceeding the limit for Class 1. This appliance is classified as a CLASS 1 LASER product. The CLASS 1 LASER PRODUCT MARKING is located on the rear exterior. This caution label is located inside the unit. SERVICING NOTE NOTES ON HANDLING THE OPTICAL PICK-UP BLOCK OR BASE UNIT The laser diode in the optical pick-up block may suffer electrostatic break-down because of the potential difference generated by the charged electrostatic load, etc. on clothing and the human body. During repair, pay attention to electrostatic break-down and also use the procedure in the printed matter which is included in the repair parts. The flexible board is easily damaged and should be handled with care. NOTES ON LASER DIODE EMISSION CHECK The laser beam on this model is concentrated so as to be focused on the disc reflective surface by the objective lens in the optical pick- up block. Therefore, when checking the laser diode emission, observe from more than 30 cm away from the objective lens. SAFETY-RELATED COMPONENT WARNING!! COMPONENTS IDENTIFIED BY MARK ! OR DOTTED LINE WITH MARK ! ON THE SCHEMATIC DIAGRAMS AND IN THE PARTS LIST ARE CRITICAL TO SAFE OPERATION. REPLACE THESE COMPONENTS WITH SONY PARTS WHOSE PART NUMBERS APPEAR AS SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUBLISHED BY SONY. Tuner section FM stereo, FM/AM superheterodyne tuner FM tuner section Tuning range 87.5 – 108.0 MHz Antenna FM lead antenna Antenna terminal 75 Ω unbalanced Intermediate frequency 10.7MHz AM tuner section Tuning range European, Australian and South African models: 531 – 1,602 kHz Other models: 530 – 1,710 kHz Antenna AM loop antenna Antenna terminals External antenna terminal Intermediate frequency 450 kHz General Power requirements Mexican model: 120 V AC, 50/60 Hz Australian and South African models: 220 – 240 V AC, 50/60 Hz Other models: 120V AC, 60Hz Power consumption 80 W Dimensions (w/h/d) incl. projecting parts and controls Approx. 280 × 320 × 371 mm (11 1/8 × 12 5/8 × 14 5/8 in) Mass Approx. 7.2 kg (15 lb 14 oz.) Supplied accessories: AM loop antenna (1) Remote RM-SG5 (1) FM lead antenna (1) Design and specifications are subject to change without notice. ATTENTION AU COMPOSANT AYANT RAPPORT À LA SÉCURITÉ! LES COMPOSANTS IDENTIFÉS PAR UNE MARQUE ! SUR LES DIAGRAMMES SCHÉMATIQUES ET LA LISTE DES PIÈCES SONT CRITIQUES POUR LA SÉCURITÉ DE FONCTIONNEMENT. NE REMPLACER CES COMPOSANTS QUE PAR DES PIÈSES SONY DONT LES NUMÉROS SONT DONNÉS DANS CE MANUEL OU DANS LES SUPPÉMENTS PUBLIÉS PAR SONY. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com — 3 — SAFETY CHECK-OUT After correcting the original service problem, perform the following safety checks before releasing the set to the customer: Check the antenna terminals, metal trim, “metallized” knobs, screws, and all other exposed metal parts for AC leakage. Check leakage as described below. LEAKAGE The AC leakage from any exposed metal part to earth Ground and from all exposed metal parts to any exposed metal part having a return to chassis, must not exceed 0.5 mA (500 microampers). Leakage current can be measured by any one of three methods. 1. A commercial leakage tester, such as the Simpson 229 or RCA WT-540A. Follow the manufacturers’ instructions to use these instruments. 2. A battery-operated AC milliammeter. The Data Precision 245 digital multimeter is suitable for this job. 3. Measuring the voltage drop across a resistor by means of a VOM or battery-operated AC voltmeter. The “limit” indication is 0.75 V, so analog meters must have an accurate low-voltage scale. The Simpson 250 and Sanwa SH-63Trd are examples of a passive VOM that is suitable. Nearly all battery operated digital multimeters that have a 2V AC range are suitable. (See Fig. A) To Exposed Metal Parts on Set 0.15 µF 1.5 kΩ AC Voltmeter (0.75 V) Earth Ground Fig. A. Using an AC voltmeter to check AC leakage. TABLE OF CONTENTS 1. GENERAL .......................................................................... 4 2. DISASSEMBLY 2-1. CD Door ............................................................................. 5 2-2. CD Mechanism Deck ......................................................... 5 2-3. Front Panel ......................................................................... 6 2-4. Main Board and H.P Board ................................................ 6 2-5. CD Tray .............................................................................. 7 2-6. CD Decoder Board ............................................................. 7 2-7. Base Unit ............................................................................ 8 2-8. Cassette Lid (L)/(R)............................................................ 8 3. MECHANICAL ADJUSTMENTS ............................... 9 4. ELECTRICAL ADJUSTMENTS ................................. 9 5. DIAGRAMS 5-1. Circuit Boards Location ................................................... 14 5-2. Brock Diagrams • Deck Section ................................................................... 15 • Tuner/CD Section............................................................ 17 5-3. IC Brock Diagrams ........................................................... 19 5-4. Schematic Diagram —Main Section — ........................... 24 5-5. Printed Wiring Board — Main Section — ....................... 29 5-6. Printed Wiring Board —CD Section — ........................... 34 5-7. Schematic Diagram —CD Section — .............................. 39 5-8. Schematic Diagram — Panel Section — ......................... 43 5-9. Printed Wiring Board —Panel Section — ........................ 47 5-10. IC Pin Function ................................................................ 52 6. EXPLODED VIEWS 6-1. Cabinet Section................................................................. 54 6-2. Front Panel Section .......................................................... 55 6-3. Cassette Button Section .................................................... 56 6-4. Cassette Mechanism Deck Section................................... 57 6-5. CD Mechanism Deck Section 1 ....................................... 58 6-6. CD Mechanism Deck Section 2 ....................................... 59 6-7. Base Unit Section (KSM-213BCM)................................. 60 7. ELECTRICAL PARTS LIST ........................................ 61 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com — 4 — SECTION 1 GENERAL LOCATION OF PARTS AND CONTROLS 1 Disc tray 2 DISC 1 button 3 DISC 2 button 4 DISC 3 button 5 DISC SKIP button 6 § OPEN/CLOSE button 7 DBFB button 8 VOLUME knob 9 Display window !º CLOCK TIMER SET button !¡ TIMER ON/OFF button !™ DISPLAY DEMO !£ TUNER/BAND !¢ · ∏ (play/pause) button !∞ ENTER/NEXT button !§ ≠ ± CD AMS/TUNER PRESET TIMER SET buttons !¶ FILE SELECT !• I/u (POWER) button !ª TUNER MEMORY REPEAT button @º EDIT button @¡ STEREO/M NO, PLAY MODE button @™ TAPE button @£ π (STOP) button @¢ 0 ) CD/TUNER button @∞ PHONES jack @§ Deck A, PLAY/REC @¶ Deck B, PLAY @• Tape operaying buttons r (recording) ( (play) 0 (fast rening) ) (fast forward) p 6 (stop/eject) P (pause) 7 !¶� 1 2 3 4 5 6 9 !§� !∞� !¢� 8 !£� !™� !¡� !•� !º� !ª� @º� @¡� @™� @£� @¢� @∞� @§� @•� @¶� www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com — 5 — SECTION 2 DISASSEMBLY Two craws 1 Pull out the CD tray and remove the CD door with releasing claws into the direction of arrow. 2 CD door 2-1. CD DOOR Note : Follow the disassembly procedure in the numerical order given. 6 CD mechanism deck 1 Two screws (+B 3 × 8) 3 Two screws (+BVTP 3 × 10) 2 Screw (+PTPWH 3 × 10) 2 Screw (+PTPWH 3 × 10) 4 Flat type wire (CN09) 5 Harness (CN302) 2-2. CD MECHANISM DECK www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com — 6 — 7 Screw (+PTPWH 3 × 10) 3 Screw (+BVTP 3 × 10) 4 Screw (+BVTP 3 × 10) 5 Two screw (+BVTP 3 × 10) 6 Two screws (+BVTP 3 × 10) 7 Screw (+PTPWH 3 × 10) 8 Screw (+BVTP 3 × 10) 2 Three screws (+BVTP 3 × 10) 1 Connector (CN401) 9 Front panel HOW TO SET THE POWER CORD power cord 1 Harness (CN303) 8 H.P board 2 Harness (CN204) 3 Connector 4 Connector (CN202) 5 Connector (CN201) 7 MAIN board 6 Two screws (+KTP 3 × 8) Craw 2-3. FRONT PANEL 2-4. MAIN BOARD AND H.P BOARD www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com — 7 — 1 Screw (+P 2.6 × 4) 2 Bracket 4 Bracket 5 Flat type wire (CN06) 3 Screw (+P 2.6 × 4) 6 CD tray 1 Two screws (+BVTP 3 × 10) 2 Two screws (+BVTP 3 × 10) Two craws 7 CD DECODER board 3 Belt 6 Flat type wire (CN06) 5 Flat type wire (CN01) 4 Connector (CN05) !º Connector (CN03) 8 Two screw (+BVTP 3 × 10) 9 Sheet Craw Craw 2-5. CD TRAY 2-6. CD DECODER BOARD www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com — 8 — 2 Screw (+PTPWH 2.6 × 8) 3 UD-gear 4 Screw (+PTPWH 2.6 × 8) 5 UD-Cam 8 Spring 7 Spring 6 Spring 1 Two screws (+KTP 3 × 8) 9 Base unit Four craws Four craws 2 Cassette lid (R) 1 Cassette lid (L) 2-7. BASE UNIT 2-8. CASSETTE LID (L) / (R) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com — 9 — Precaution 1. Clean the following parts with a denatured alcohol-moistened swab: record/playback head pinch rollers erase head rubber belts capstan idlers 2. Demagnetize the record/playback head with a head demagnetizer. 3. Do not use a magnetized screwdriver for the adjustments. 4. After the adjustments, apply suitable locking compound to the parts adjusted. 5. The adjustments should be performed with the rated power supply voltage unless otherwise noted. Torque Measurement SECTION 3 MECHANICAL ADJUSTMENTS Meter reading 40 to 70 g • cm (0.56 - 0.97 oz • inch) 1 to 5 g • cm (0.01 - 0.07 oz • inch) 55 to 140 g • cm (0.76 - 1.94 oz • inch) Torque FWD FWD back tension FF/REW Torque meter CQ-102C CQ-102C CQ-201B SECTION 4 ELECTRICAL ADJUSTMENTS 1. Demagnetize the record/playback head with a head damagnetizer. 2. Do not use a magnetized screwdriver for the adjustments. 3. After the adjustments, apply suitable locking compound to the parts adjusted. 4. The adjustments should be performed with the rated power supply voltage unless otherwise noted. 5. The adjustments should be performed in the order given in this service manual. (As a general rule, playback circuit adjustment should be completed before performing recording circuit adjustment.) 6. The adjustments should be performed for both L-CH and R- CH. Record/Playback Head Azimuth Adjustment (Deck A, Deck B) Note: Perform this adjustments for both decks. Procedure: 1. Mode : Playback DECK SECTION 0 dB=0.775V Tape P-4-A100 WS-48B Signal 10 kHz, –10 dB 3 kHz, 0 dB Used for Azimuth Adjustment Tape Speed Adjustment test tape P-4-A100 (10kHz, –10dB) SPEAKER terminal (JK501) level meter + – set www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com — 10 — 2. Turn the adjustment screw and check output peaks. If the peaks do not match for L-CH and R-CH, turn the adjustment screw so that outputs match within 2 dB of peak. 3. Mode: Playback 4. After the adjustments, apply suitable locking compound to the parts adjusted. Adjustment Location: Remove the cassette lid before adjustment (See page 8) test tape WS-48B (3kHz, 0dB) Tape Speed Adjustment (Deck A) Procedure: 1. Mode: Playback 2. Adjust the SFR201 so that the frequency counter reads 3,000 Hz ± 90Hz. Adjustment Location: MAIN board Sample Value of Wow and flutter W. RMS (JIS) within 0.3% (test tape: WS-48B) [MAIN BOARD] — Component side — CN204 L-CH peak R-CH peak screw position output level within 2dB within 2dB L-CH peak screw position R-CH peak test tape P-4-A100 (10kHz, –10dB) SPEAKER terminal (JK501) (L-CH) set L R oscilloscope SPEAKER terminal (JK501) (R-CH) Waveform of oscilloscope in phase 45˚ 90˚ 135˚ 180˚ good wrong SPEAKER terminal (JK501) set frequency counter + – SFR201 Tape Speed Adjustment screws REC/PB head (deck A) or PB head (deck B) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com — 11 — TUNER SECTION 0 dB=1µV AM Tuning Voltage Adjustment Procedure: 1. Set the reception frequency of the unit to 530 kHz. 2. Adjust L105 for 1.2 ± 0.05 V reading on the DC voltmeter. 3. Set the reception frequency of the unit to 1,710 kHz. 4. Confirm that the voltage reading on the DC voltmeter is within 8.0 ± 0.5 V. Adjustment Location: MAIN board (See page 12) AM Tracking Adjustment Procedure: 1. Tune the set to 600 kHz. 2. Set the output of AM RF SSG so that the input level of the set will become 60 dB (µV/m). 3. Adjust L104 so that when the waveform on the oscilloscope is maximum, no noise appears. 4. Tune the set to 1,400 kHz. 5. Adjust TC102 so that when the waveform on the oscilloscope is maximum, no noise appears. • Repeat the procedures in each adjustment several times, and the tracking adjustment should be finally done by the trimmer capacitors. Adjustment Location: MAIN board (See page 12) FM Tuning Voltage Adjustment DC voltmeter Procedure : 1. Set the reception frequency of the unit to 87.5 MHz. 2. Adjust L103 for 1.2 ± 0.05V reading on the DC voltmeter. 3. Set the reception frequency of the unit to 108 MHz. 4. Confirm that the voltage reading on the DC voltmeter is within 7.8 ± 0.5V. Adjustment Location: MAIN board (See page 12) TP1 + IF G VT Main board DC voltmeter Main board – F G VT TP1 + – AM RF SSG loop antenna set loop antenna (Supplied accessories) 60 cm AM ANTENNA terminal (TM1) 30% amplitude modulation by 400 Hz signal Field strength dB (µV/m) =SSG output level dB (µV/m) –26 dB. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com — 12 — FM Tuned Level Adjustment set Procedure: 1. Supply a 28 dB 98 MHz signal from the ANTENNA terminal. 2. Tune the set to 98 MHz. 3. Adjust SFR101 to the point (moment) when the TUNED indicator will change from going off to going on. Adjustment Location: MAIN board FM Tracking Adjustment Procedure: 1. Tune the set to 90 MHz. 2. Adjust L102 so that when the waveform on the oscilloscope is maximum, no noise appears. 3. Tune the set to 106 MHz. 4. Adjust TC101 so that when the waveform on the oscilloscope is maximum, no noise appears. • Repeat the procedures in each adjustment several times, and the tracking adjustment should be finally done by the trimmer capacitors. Adjustment Location: MAIN board Adjustment Location [MAIN BOARD] — Component side — JK501 JK101 L105 TC102 L104 IC101 L102 L103 TC101 SFR101 IC102 TP1 IC103 AM Tracking AM Tuning Voltage FM Tuning Voltage FM Tracking FM Tuned Level Carrier frequency : 90 MHz, 106 MHz Modulation : AUDIO 1kHz, 75kHz deviation (100%) Output level : 20 dB (at 75 Ω open) FM RF SSG Carrier frequency : 98 MHz Modulation : AUDIO 1 kHz, 75 kHz deviation (100%) Output level : 28 dB (at 75 Ω open) FM ANTENNA terminal (JK101) 75 Ω coaxial FM ANTENNA terminal (JK101) SPEAKER terminal (JK501) FM RF SSG set oscilloscope www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com — 13 — IC03 VR02 VR01 R07 IC01 CN12 Focus Gain Focus Bias RF Level CD SECTION Note: 1. CD Block is basically constructed to operate without adjustment. Therefore, check each item in order given. 2. Use YEDS-18 disc (3-702-101-01) unless otherwise indicated. 3. Use an oscilloscope with more than 10MΩ impedance. 4. Clean the object lens by an applicator with neutral detergent when the signal level is low than specified value with the following checks. 5. Adjust the focus bias adjustment when optical block is replaced. Focus Bias Adjustment RF Level Check Procedure : 1. Connect oscilloscope to test point TP (RF) on CD DECODER board. 2. Turned Power switch on. 3. Put disc (YEDS-18) in and playback. 4. Confirm that oscilloscope waveform is clear and check RF signal level is correct or not. Note: Clear RF signal waveform means that the shape “◊” can be clearly distinguished at the center of the waveform. oscilloscope level: 1.0 Vp-p VOLT/DIV: 200 mV TIME/DIV: 500 nS +0.3 –0.2 Adjustment Location: CD DECODER board Procedure: 1. Connect DC voltmeter to test point CN12 (FEO), (VC) on CD DECODER board. 2. Turned Power switch on. 3. Put disc (YEDS-18) in and stop. 4. Adjust VR01 so that the DC voitmeter reading is 0 ± 20 mV. Adjustment Location: CD DECODER board Focus Gain Adjustment (VR02) This gain has a margin, so even if it is slightly off. There is no problem. Therfore, do not perform this adjusment. Please note that it should be fixed to mechanical center position when you moved and do not know original position. Adjustment Location [CD DECODER BOARD] — Component side — CD DECODER board CN12 FEO VC DC voltmeter + – CD DECODER board TP (RF) CN12 (VC) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com — 14 — SECTION 5 DIAGRAMS 5-1. CIRCUIT BOARDS LOCATION SW (C) board SW (D) board SW (B) board DISK board PANEL board CD DECODER board H.P board SENSOR board R/P SWITCH board VR board AC POWER board MAIN board SW (A) board MOTOR board MOTOR (6P) (S) board www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com HCD-GRX2/RX33 5-2. BLOCK DIAGRAMS — DECK SECTION — — 15 — — 16 — HP901 PB HEAD TAPE B HRP901 REC/PB HEAD TAPE A R CH R CH R CH PLAY/REC CONTROL Q203, 205 PLAY/REC CONTROL DRIVE Q207 MUTE SWITCH Q216 TAPE A/B SWITCH Q213 PLAY/REC CONTROL D209 L201 BIAS OSC BIAS OSC Q218 HE901 ERASE HEAD R CH 1 2 9 3 REC OUT PB OUT A/B 5 19 11 10 REC/PB EQ AMP IC201 TAPE A/B Q209 MUTE TAPE A SWITCH Q214 Q211 Q220 REC SWITCH MUTE CONTROL Q Q217 D205 D203 D202 D212 D210 D211 D210 S201 A DECK S202 B DECK S203 PLAY M D207 D206 M901 REC/CAPSTAN MOTOR TAPE SPEED SFR201 +11.5V D208 SW201 REC/PLAY PLAY REC : FM : CD • Signal Path • RCH is omitted B CD SECTION TU L 11 9 Q301 10 ST IND TU MUTE DO CD L 12 CONTROL 3 2 1 CLK 14 DI 15 CE 13 SELECTOR IC301 CLK DI CE LINE AMP IC302 7 5 BASS BOOST SWITCH Q307 Q303 MUTE 13 2 7 4 POWER AMP IC501 SPEAKER RELAY DRIVE Q551 Q553 1 2 6 IC502 IC502 RL501 R CH SPEAKER PHONES JK501 JK303 SCOR SENS SQSO XLAT SQCK DATA DI CLK CE STB 26 STB 21 CE 22 CLK 23 DI 18 DATA 17 SQCK 20 XLAT 19 SQSO 51 SENS 38 SCOR MUTE DRIVE Q583,584 Q604 MUTE MUTE SWITCH Q603 CD SYNC SWITCH Q208 4 TU MUTE 24 DI1 48 SYS REC 7 DBFB 3 SYSTEM MUTE 2 POWER LED DRIVE IC602 2 3 4 36 ALATCH 11 13 LED DRIVE DI CLK Q208 Q605,606 RESET SWITCH POWER DOWN DET Q601 10 RESET 15 POWER DOWN Q602 LED602 LED601 Q602 D602 X2 11 X1 12 VR UP 44 X601 4.19MHz VR DOWN 45 VR601 ENCODER PIC UP 55 PIC DOWN 56 TRAY OPEN 59 TRAY CLOSE 60 TURN TABLE 58 DISC COUNT 57 A B S02 TRAY OPEN/CLOSE DET S03 DISC COUNTER DET S04 TURNTABLE OPERATION DET S01 CD DECK UP/DOWN DET 3 2 Q601 RM601 REMOTE CONTROL RECEIVER 39 REMOTE 64 78 KEY MATRIX S601-623 P1 P21 100 86 G1 G15 . 81 85 33 29 KI0 KI4 FLD601 FLD DISPLAY SYSTEM CONTROLLER/ FLD DRIVER IC601 +5.6V REG Q404 SITCHING Q406,407 +11.5V (SWITCHED) +11.5V FILTER Q402 +7.9V REG Q403 +7.9V +12V REG Q401 RECT D405-408 MUTE Q585,586 P MUTE CONT Q409 AC OFF DET Q410 D417 D416 D553 RECT D401 D409 -12V -30V +30V -27V REG Q408 -27V VOLTAGE DOUBLER D414,415 AC IN PT001 AC3.4V AC3.4V 12 16 A TUNER SECTION : PB (DECK A) : PB (DECK B) : REC (DECK A) Q207 Q201 CE CLK DI COUNT FOK 52 FOK 53 COUNT 47 FM ST IND w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com HCD-GRX2/RX33 — TUNER/CD SECTION — — 17 — — 18 — CE 19 12 5 3 4 2 24 1 PLL IC103 FM XO XI CLK DI DO CE CLK DI DO OPTICAL PICK-UP BLOCK APC Q01 38 +5V VC LD GND A C B E F FOCUS COIL F+ F T+ T TRACKING COIL 33 34 39 36 35 48 APC FOCUS PHASE COMPENSATION DECODER SERIAL/ PARALLEL CONVERTER FE AMP RF AMP IIL TTL TTL IIL COMAND VC TRACKING PHASE COMPENSATION LD PD E F PD1 PD2 6 24 23 20 19 22 21 31 25 SENS RFO FOK C OUT DATA XLT CLK XRST 13 FEO TAO IC03 T.T/TRAY MOTOR DRIVER CD RF/SERVO PROSSESOR IC01 (1/2) 4 5 T IN 3 2 1 VR PD PD 18 17 20 19 6 F IN 22 SL IN 13 T.T F IN F+ F T+ T SL+ SL SP+ SP M M MOTOR M102 SLED MOTOR M101 SPINDOL EFM DEMO. XRST CLV SERVO DIGITAL CLV D/A I/F SUB CODE PROSSESOR CPU I/F 9 11 5 4 7 6 1 MDP SENS SCOR SQSO SQCK CLOCK DATA CLK XLT DAT SE CN FOK RF SERIAL I/F PWM PWM 70 69 73 74 NL L XTA1 XTA0 X701 MUTE R-CH CD DIGITAL SIGNAL PROCESSOR IC04 16 :FM :CD • SIGNAL PATH 14 7 8 4 2 1 6 10 DETECTOR 16 OSC FM 75Ω AM ANTENNA JK101 D101 L101 FM ANT L102 FM RF 3 1 RF MIX 6 8 FM FRONT END IC101 RF IF AMP Q101 CF101 10.7MHz T101 CF102 10.7MHz FM OSC AMP Q102 D103 L103 L105 MW OSC IF G VT AM/FM TUNING VOLTAGE TP1 L104 AM ANT AM RF AMP Q104 MPX 16 FM IF 1 OSC 23 AFC 22 AM RF 21 FM IF AF DET 18 FM DET AM/FM IF BUFF AM OSC AM MIX AM DET SMET 20 CF103 450kHz MUTE AGC AM IF DECODER 14 L 15 R 4 2 T102 AM IFT 8 FM DET 17 MPX VCO CF104 10.7MHz CF105 19kHz R CH FM/AM MPX IC102 L.P.F Q105,106 FM TUNED LEVEL PD1 21 X201 7.2MHz FM B+ 17 TUB+ B+ Q103 PL DET 13 18 AM OSC/FMSD 24 B+ 7 SD PH DET 11 PH DET 12 14 ST/MONO TU LED 6 13 AM/FM SD 15 L CTR 16 R CTR 7 ST IND 10 AM/FM MUTE Q109 TU L ST IND TU MUTE DO A MAIN SECTION D 5 LD ON SWITCH Q02 LD PD F/T COIL SL/SP MOTOR CN12 CN2 ATSC 45 FEO 1 TEO 42 FOCUS TRACKING 37 40 FE BIAS EI RV01 FOCUS GAIN RV02 14 15 30 31 T.T+ T.T TR+ TR M M MOTOR T/T MOTOR TRAY 21 SP IN 29 TR F IN 12 T.T R IN 28 TR T IN 27 MUTE IN IC06 IC01 (2/2) 6 7 REG Q11 9 REG I 10 REG B 11 REG OUT 7 VCC 8 VCC +5V +7.5V XRST 6 SPEED 11 CONTRL 5 SWITCH Q04 13 14 TR+ TR 7 14 T.T+ T.T 4 MUTE 2 DATA 3 CLOK 1 STB IC02 MOTOR DRIVE REG CONTROL T.T/TRAY 36 23 14 13 15 16 17 8 25 18 SPOA LIMIT SWITCH S05 10 XLAT CLOCK GEN. PWM PWM 77 78 NR R 22 XLON 1 3 2 IC05 MIX AMP MUTE Q311 CD L SCOR SENS SQSO XLAT SQCK DATA CE STB CLK DI B MAIN SECTION :AM • RCH is omitted SFR101 CLK DI COUNT FOK w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com HCD-GRX2/RX33 — 19 — — 20 — — 21 — — 22 — — 23 — FM IF REG GND VCC FM DET S-CURVE TUNING DRIVE LEVEL DET AM/FM IF BUFE ALC BUFFER AM OSC AM MIX AM RF AMP AGC AM DET AM IF COMP FM AM MUTE DECORDER STEREO DRIVE FF TRIG PHASE DET VCO AM/FM SW PILOT DET STEREO SW 3 6 9 12 2 5 8 11 1 4 7 10 22 19 16 13 23 20 17 14 24 21 18 15 OSC/FMSD OSC AFC AM RF SMET AM HPF AF DET MPX VCO MPX IN R OUT L OUT PL DET FM IF AM MIX REG AM IF GND TU LED ST IND FM DET VCC AM/FM PH DET PH DET XIN CE DI CL DO SYC IN0 IN1 OUT0 OUT1 OUT2 OUT3 SHIFT REGISTER LATCH 12 BIT PROGRAMMABLE DIVIDER SWALLOW COUNTER 1/16 . 1/17 BIT REFERENCE DIVIDER PHASE DETECTOR CHARGE PUMP 1 / 2 X OUT VSS PD2 PD1 VDD FM IN AM IN OUT 6 HCTR LCTR OUT 5 OUT 4 UNIVERSAL COUNTER 7 10 11 12 9 8 6 5 4 3 2 1 13 14 24 23 22 21 20 19 18 17 16 15 + – 3 6 9 12 15 2 5 8 11 14 1 4 7 10 13 28 25 22 19 16 29 26 23 20 17 30 27 24 21 18 + – + – + – LATCH DECODER CONTROL SHIFT REGISTER – + LVROUT LVRIN LTOUT LTCOM LT4 LT3 LT2 LT1 L4 L3 L2 L1 VDD CL DI RVROUT RVRIN RTOUT RTCOM RT4 RT3 RT2 RT1 R4 R3 R2 R1 VREF VSS CE CH2/A CH2/B NF VCC CG NF ALC METAL OUT PRE OUT TAPE A /TAPE B REC OUT REC IN CH1/A CH1/B NF GND1 M/H NF CH2 CH2 ALC M/N CH1 GND GND CH1 + – + – + – + – A/B GND METAL OUT PRE OUT MIX OUT REC OUT REC IN IREF VREF2 VREF1 24 23 22 21 20 19 18 17 16 15 14 13 1 2 3 4 5 6 7 8 9 10 11 12 DRIVER DRIVER GND MUTE CONTROL XRST T.T(M) POSI.1 POSI.2 T.T.SW VDD STB CLOK DATA I DATA 0 LOADING M- LOADING M+ SENSOR 1 8 2 3 4 5 6 7 16 9 15 T C 14 13 12 11 10 SERIAL I/O CONTROL LATCH LATCH LATCH 36 PHD2 PHD1 PHD 33 LD 32 RF M 31 RF O 30 RF I 29 CP 28 CB 27 CC1 26 CC2 25 FOK 24 SENS 23 C. OUT 22 XRST 21 DATA 20 XLT 19 CLK 18 VCC 17 ISET 16 SL 0 15 SL M 14 SL P 13 12 TA O TA M 11 FSET 10 TG2 9 TGU 8 SRCH 7 FE M 6 FE O 5 FLB 4 FGD 3 FDFCT 2 FEI 1 FEO 48 VC 47 TDFCT 46 TZC 45 ATSC 44 TEI 43 LPFI 42 TEO 41 VEE 40 EI 39 E 38 F 37 FE BIAS + + – + + – + – + – + – + – + – + + + – + – + – + – + – + – + – + – – + + – – + + – + – + – + – + – APC – – – – LEVELS FOK MIRR DFCT RF IV AMP2 RF IV AMP1 FE AMP F IV AMP E IV AMP TE AMP FZC COMP BAL1 BAL2 BAL3 TOG1 TOG2 TOG3 TTL IIL IIL TTL TTL IIL • IIL DATA RESISTOR • INPUT SHIFT RESISTOR • ADDRESS DECODER • OUTPUT DECODER HPF COMP LPF COMP TZC COMP DFCT DFCT TM1 FS4 ATSC • WINDOW COMP • FCS PHASE COMPENSATION • TRACKING • PHASE COMPENSATION • ISET FS1 FS2 TM4 TM5 TM6 TM3 TM7 TG2 • F SET TG1 TM2 + – TOG1-3 FS1-4 TG1-2 TM1-7 PS1-4 BAL1-3 35 34 IC01 (CD DECORD BOARD) CXA1782BQ IC102 (MAIN BOARD) LA1831 IC103 (MAIN BOARD) LC7218-ST IC301 (MAIN BOARD) LC75392 IC201 (MAIN BOARD) TA8189N IC02 (CD DECORD BOARD) TC9173P 5-3. IC BLOCK DIAGRAMS + – LEVEL SHIFT + – + – 1 2 3 4 5 6 7 8 9 10 11 12 13 14 28 27 LEVEL SHIFT + – + – MUTE + – + – LEVEL SHIFT + – + – LEVEL SHIFT + – + – + – 15 16 17 18 19 21 20 22 26 25 24 23 + – NC Vcc Vcc Vcc VCC BIAS IN IN1B IN1A IN2B IN2A GND GND MUTE VCC OUT2A OUT2B OUT1A OUT1B IN4B IN4A IN3B IN3A OP OUT OP IN (–) OP IN (+) GND NC VCC OUT3A OUT3B OUT4A OUT4B 1 2 3 4 5 6 7 8 9 10 16 15 14 13 12 11 CONTROL CIRCUIT 12 BIT SHIFT REGISTER 12 BIT STORAGE REGISTER OUTPUT BUFFER (OPEN DRAIN) 17 18 VDD OE Q11 Q10 Q9 Q8 Q7 Q6 Q5 Q4 Q3 Q2 Q1 Q0 LCK CLOCK DATA VSS IC03 (CD DECORD BOARD) BA5941FP IC602 (PANEL BOARD) BU2092 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 5-10. IC PIN FUNCTION Pin No. 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 I/O — O O O O O O O O — I I — — I — O O I O O O O I — O O — I I I I I O — O O I I — O I O I I — I I I I Pin Name VDD POWER OUT S. MUTE OUT TU. MUTE OUT TUNED OUT TAPE REC OUT DBFB NORMAL NC NC RESET X2 X1 VSS NC POWER DOWN IN VDD SOCK DATA SOSO XLAT CE CLK DO DI VSS CD STB FLAT VSS K4 K3 K2 K1 K0 AVDD AVREF A LATCH B LATCH SCOR REMOTE IN VSS NC VSS DECK STB VR UP VR DOWN VDD FM ST IN SYNC REC IN VSS VSS Pin No. 51 52 53 54 55 56 57 58 59 60 61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80 81 82 83 84 85 86 87 88 89 90 91 92 93 94 95 96 97 98 99 100 I/O I I I — I I I I I I I O I O O O O O O O O O O O O O O O — O O O O O O O O O O O O O O O O O O O O O Description Input from CXD2508A SENS Input from CXD2508A FOK. OK: H, Others: L Input from CXD2508A COUNT Ground Input from CD mechanism pick up switch. Up: L, Others: H Input from CD mechanism pick down switch. Down: L, Others: H Input from CD mechanism disc count switch. Count: L, Others: H Input from CD mechanism turn table switch. ON: L, OFF: H Input from CD mechanism tray open switch. Open: L, Others: H Input from CD mechanism tray close switch. Open: L, Others: H AMS signal input. During program: H, Interval between programs: L Serial mute (tuner) output (Not used) Input from destination select mode switch. ON: H, OFF: L FLD segment signal output P1. ON: H, OFF: L FLD segment signal output P2. ON: H, OFF: L FLD segment signal output P3. ON: H, OFF: L FLD segment signal output P4. ON: H, OFF: L FLD segment signal output P5. ON: H, OFF: L FLD segment signal output P6. ON: H, OFF: L FLD segment signal output P7. ON: H, OFF: L FLD segment signal output P8. ON: H, OFF: L FLD segment signal output P9. ON: H, OFF: L FLD segment signal output P10. ON: H, OFF: L FLD segment signal output P11. ON: H, OFF: L FLD segment signal output P12. ON: H, OFF: L FLD segment signal output P13. ON: H, OFF: L FLD segment signal output P14. ON: H, OFF: L FLD segment signal output P15. ON: H, OFF: L (–) negative power supply FLD segment signal output P16. ON: H, OFF: L FLD segment signal output P17. ON: H, OFF: L FLD segment signal output P18. ON: H, OFF: L FLD segment signal output P19. ON: H, OFF: L FLD segment signal output P20. ON: H, OFF: L FLD segment signal output P21. ON: H, OFF: L FLD grid signal output 15. ON: H, OFF: L FLD grid signal output 14. ON: H, OFF: L FLD grid signal output 13. ON: H, OFF: L FLD grid signal output 12. ON: H, OFF: L FLD grid signal output 11. ON: H, OFF: L FLD grid signal output 10. ON: H, OFF: L FLD grid signal output 9. ON: H, OFF: L FLD grid signal output 8. ON: H, OFF: L FLD grid signal output 7. ON: H, OFF: L FLD grid signal output 6. ON: H, OFF: L FLD grid signal output 5. ON: H, OFF: L FLD grid signal output 4. ON: H, OFF: L FLD grid signal output 3. ON: H, OFF: L FLD grid signal output 2. ON: H, OFF: L FLD grid signal output 1. ON: H, OFF: L Pin Name SENS FOK COUNT VSS PIC UP PIC DOWN DISC COUNT SW TURN TABLE SW TRAY OPEN SW TRAY CLOSE SW VSS SERI MUTE (TUNER) MODE SW IN P1 P2 P3 P4 P5 P6 P7 P8 P9 P10 P11 P12 P13 P14 P15 –V LOAD P16 P17 P18 P19 P20 P21 G15 G14 G13 G12 G11 G10 G9 G8 G7 G6 G5 G4 G3 G2 G1 SECTION 6 EXPLODED VIEWS NOTE: • -XX, -X mean standardized parts, so they may have some differences from the original one. • Items marked “*” are not stocked since they are seldom required for routine service. Some delay should be anticipated when ordering these items. When indicating parts by reference number, please include the board name. The components identified by mark ! or dotted line with mark ! are critical for safety. Replace only with part number specified. Les composants identifiés par une marque ! sont critiques pour la sécurité. Ne les remplacer que par une pièce portant le numéro spécifié. 1 4-210-302-01 RUBBER, FOOT 2 4-210-292-01 DOOR, CD 3 4-210-297-01 CABINET * 4 A-4405-471-A MAIN BOARD, COMPLETE * 5 1-670-391-11 AC POWER BOARD !6 1-559-583-11 CORD, POWER (US, CND) !6 1-551-506-99 CORD, POWER (MX, SAF) !6 1-696-966-11 CORD, POWER (AUS) 7 4-210-299-01 WASHER, AC CORD 8 4-210-301-01 FOOT (B) * 9 4-210-298-01 CHASSIS !PT302 1-431-939-11 TRANSFORMER, POWER (US, CND) !PT302 1-431-961-11 TRANSFORMER, POWER (MX, SAF) !PT302 1-431-962-11 TRANSFORMER, POWER (AUS) Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks — 52 — — 53 — — 54 — 6-1. CABINET SECTION IC601 µPD780205GF (SYSTEM CONTROL) / PANEL BOARD Description VDD Power switch output. ON: H, OFF: L System mute output. ON: H, OFF: L Tuner mute output. ON: H, OFF: L Surround output. ON: H, OFF: L (Not used) Function tape output. Tape: H, Others: L (Not used) DBFB normal (U2: DBFB). ON: H, Others: L DBFB high. ON: H, Others: L (Not used) Not used Reset input X’tal 4.194314 MHz X’tal 4.194314 MHz Ground Not used (open) Power down input. AC ON: H, AC OFF: L VDD CXD2508A SQCK, CLOCK output CXD2508A data output CXD2508A SQSO input CXD2508A XLAT output. Latch: L, Others: H Chip enable output to LC7218, LC75392. Data: H, Address: L CLK output Data output Data input Ground STB output to SN74HC4094. STB: L, Others: H Flat output. Flat: H, Others: L (Not used) Ground Key input 4 to A/D Key input 3 to A/D Key input 2 to A/D Key input 1 to A/D Key input 0 to A/D VDD of A/D converter Reference voltage of A/D converter Latch output to BU2092. Latch: H, Others: L Not used CXD2508A SCOR Remote signal input. ON: H, OFF: L Ground Shift or load output to SN74HC165. Shift: H, Load: L (Not used) Data input to SN74HC165 (Ground) STB output to BU2114, SN74HC4094. STB:H, Others: L (Not used) VR encoder A input. ON:L, OFF: H VR encoder B input. ON:L, OFF: H VDD FM stereo indicator input. Stereo:L, Mono: H Synchro record input. Record:L, Other: H CD encoder A input. ON: L, OFF: H (Ground) CD encoder B input. ON: L, OFF: H (Ground) • The mechanical parts with no reference number in the exploded views are not supplied. • Hardware (# mark) list and accessories and packing materials are given in the last of this parts list. — 55 — — 56 — Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks 6-2. FRONT PANEL SECTION 101 102 103 104 105 106 107 108 109 110 111 Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks 6-3. CASSETTE BUTTON SECTION a a not supplied not supplied not supplied PT302 not supplied not supplied not supplied CD mechanism deck 3 2 1 9 8 6 5 7 4 #2 #2 #2 #2 #2 #1 #1 #1 #1 #1 #1 #1 #1 #16 #16 #10 #10 #1 #3 #11 #11 #11 60 69 59 68 58 57 56 82 55 54 53 51 52 75 71 7286 84 87 85 62 63 64 #1 #1 #1 not supplied #1 #1 #1 #1 Cassette mechanism deck #1 #1 77 78 65 74 73 61 79 81 80 59 66 53 83 67 70 51 4-210-296-01 WINDOW (R), DOOR 52 4-210-294-01 LID (R), CASSETTE 53 4-210-326-01 SPRING, DOOR 54 4-210-295-01 WINDOW (L), DOOR 55 4-210-293-01 LID (L), CASSETTE 56 4-210-319-01 KNOB, VOLUME 57 4-210-300-01 RING, VOLUME 58 4-210-304-01 WASHER, VR 59 4-992-131-01 DAMPER (GRY), GEAR * 60 1-670-392-11 H.P BOARD * 61 1-670-387-11 DISK BOARD * 62 1-670-388-11 SENSOR BOARD 63 1-773-077-11 WIRE (FLAT TYPE) (18 CORE) * 64 A-4414-553-A PANEL BOARD, COMPLETE * 65 1-670-389-11 VR BOARD * 66 1-666-444-11 R/P SWITCH BOARD 67 4-210-307-01 PANEL, FRONT 68 4-962-708-01 EMBLEM (4-A), SONY 69 4-210-308-01 OVERAY, DISPLAY 70 4-210-309-01 WINDOW, DISPLAY 71 4-210-310-01 LENS (A), CD BUTTON 72 4-210-311-01 LENS (B), CD BUTTON 73 4-210-312-01 LENS (C), CD BUTTON 74 4-210-313-01 BUTTON (B), CD 75 4-210-314-01 BUTTON, POWER 76 4-210-315-01 BUTTON, CLOCK 77 4-210-316-01 BUTTON, FUNCTION 78 4-210-317-01 BUTTON, TUNER 79 4-210-318-01 LENS, PLAY 80 4-210-320-01 LENS, BUTTON 81 4-210-321-01 OVERAY, BUTTON 82 4-210-322-01 HOLDER (L), DOOR 83 4-210-323-01 HOLDER (R), DOOR 84 4-210-324-01 HOLDER, CD BUTTON 85 4-210-327-01 BRACKET, TOP CABINET 86 4-210-329-01 FILM, BUTTON LENS 87 4-210-330-01 PLATE, PVC 101 4-210-336-01 BUTTON (L), REC 102 4-210-337-01 BUTTON (L), PLAY 103 4-210-338-01 BUTTON (L), REW 104 4-210-339-01 BUTTON (L), FF 105 4-210-340-01 BUTTON (L), S/E 106 4-210-341-01 BUTTON (L), PAUSE 107 4-210-342-01 BUTTON (R), PLAY 108 4-210-343-01 BUTTON (R), REW 109 4-210-344-01 BUTTON (R), FF 110 4-210-345-01 BUTTON (R), S/E 111 4-210-346-01 BUTTON (R), PAUSE • Abbreviation CND : Canadian AUS : Australian MX : Mexican SAF : South African w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com — 57 — 6-4. CASSETTE MECHANISM DECK SECTION 160 161 160 158 157 161 154 163 153 154 152 153 152 151 SW202 HE901 HRP901 not supplied not supplied not supplied not supplied not supplied not supplied not supplied not supplied not supplied HP901 SW203 SW204 M901 Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks 151 9-980-286-01 CAP SCREW 2 × 7.5 152 9-980-288-01 A SCREW 2 × 7 (AZIMUTH) 153 9-980-287-01 B SCREW 2 × 3 154 9-980-276-01 PINCH ROLLER ARM ASSY 157 9-980-279-01 SCREW M COLLAR 158 9-980-278-01 MOTOR RUBBER 160 9-980-277-01 BELT (W) F 161 9-980-281-01 BELT M * 163 1-759-417-11 DECK, MECHANICAL HE901 9-980-284-01 E HEAD (ERASE) HP901 9-980-282-01 P HEAD (PLAY) HRP901 9-980-283-01 RP HEAD (REC/PLAY) M901 9-980-285-01 MOTOR (CAPSTAN/REEL) SW202 9-980-274-01 LEAF SWITCH (A DECK) SW203 9-980-274-01 LEAF SWITCH (B DECK) SW204 9-980-275-01 LEAF SWITCH (PLAY) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com — 58 — 6-5. CD MECHANISM DECK SECTION 1 Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks * 201 1-670-801-11 MOTOR BOARD 202 3-669-480-11 + PTPWH 2 203 4-992-168-01 TRAY, CHANGER BASE 204 4-992-180-01 PLATE, BLIND 205 4-992-181-01 LEVER, SENSOR (SW) 206 4-992-182-01 SPRING, SENSOR (SW) LEVER 207 4-992-170-01 BELT, LOADING 208 4-992-171-01 PULLEY, GEAR 209 4-992-179-01 GEAR, TR 210 4-992-177-01 GEAR, TR LOCK 211 4-992-178-01 GEAR (C), RELAY 212 4-992-187-01 CUSHION 213 4-992-186-01 CUSHION, SW LEVER 214 4-992-173-01 GEAR (B), RELAY 215 4-992-183-01 SCREW, RELAY GEAR (B) 216 4-992-174-01 GEAR, CHANGE 217 4-992-184-01 WASHER, CHANGE GEAR 218 4-992-176-01 SPRING, CHANGE GEAR 219 4-992-185-01 WASHER, CHANGE PLATE 220 4-992-172-01 GEAR (A), RELAY * 221 4-993-032-01 PLATE, CHANGE 222 4-993-033-01 WASHER, POLY ETHYLENE * 223 1-670-798-11 SW (B) BOARD * 224 1-670-797-11 SW (A) BOARD * 225 4-993-034-01 GUIDE, RAIL 226 4-993-140-01 TURN TABLE M103 X-4948-765-1 MOTOR ASSY (TURN TABLE) 203 223 204 209 225 225 217 215 219 214 221 211 222 218 216 220 207 210 213 212 208 206 205 201 224 212 226 202 #5 #5 M103 #5 #7 #7 #9 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com — 59 — 6-6. CD MECHANISM DECK SECTION 2 259 264 263 257 267 256 258 262 261 254 266 252 253 251 268 259 255 #1 #1 #1 #1 #7 not supplied #7 #7 #10 Base unit block #1 M104 Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks 251 1-769-856-11 WIRE (FLAT TYPE) (5 CORE) 252 4-992-190-01 UD-CAM 253 4-992-191-01 UD-GEAR 254 4-992-195-01 MAGNET * 255 4-992-196-01 CHASSIS, MAIN 256 4-992-197-01 BELT, LOADING GEAR 257 4-992-198-01 PULLEY (B), GEAR 258 4-992-199-01 GEAR, SLIDE 259 4-992-200-01 ROLLER 261 4-992-192-01 SPRING, BRAKE CAM 262 4-992-193-01 LEVER, SW * 263 1-670-800-11 SW (D) BOARD * 264 1-670-799-11 SW (C) BOARD 266 4-992-194-01 CLAMP 267 4-992-201-01 WASHER, POLYETHYLENE * 268 A-4414-924-A CD DECODER BOARD, COMPLETE M104 X-4948-766-1 MOTOR ASSY (A) (TRAY) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com — 60 — 6-7. BASE UNIT SECTION (KSM-213BCM) Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks 301 4-992-164-01 BASE, KSM MECHANICAL 302 4-992-165-01 DAMPER (GREEN) 303 4-992-166-01 DAMPER (RED) 304 4-992-167-01 SPRING, MECHANICAL BASE 305 2-626-907-01 GEAR (A) (S) 306 2-626-908-01 SHAFT, SLED 307 2-627-003-02 GEAR (B) !308 8-848-379-31 OPTICAL PICK-UP KSS-213B/S-N * 309 1-639-678-12 MOTOR (6P)(S) BOARD 310 1-783-740-11 WIRE (FLAT TYPE) (16 CORE) M101 X-2625-877-1 MOTOR ASSY (SPINDLE) M102 X-2625-769-1 MOTOR ASSY (SLED) The components identified by mark ! or dotted line with mark ! are critical for safety. Replace only with part number specified. Les composants identifiés par une marque ! sont critiques pour la sécurité. Ne les remplacer que par une pièce portant le numéro spécifié. 302 303 302 307 306 308 303 305 310 304 309 304 301 M101 M102 #6 #6 #6 #6 #18 not supplied www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com NOTE: • Due to standardization, replacements in the parts list may be different from the parts specified in the diagrams or the components used on the set. • -XX, -X mean standardized parts, so they may have some difference from the original one. • Items marked “*” are not stocked since they are seldom required for routine service. Some delay should be anticipated when ordering these items. • CAPACITORS: uF: µF • RESISTORS All resistors are in ohms. METAL: metal-film resistor METAL OXIDE: Metal Oxide-film resistor F: nonflammable • COILS uH: µH • SEMICONDUCTORS In each case, u: µ, for example: uA...: µA... , uPA... , µPA... , uPB... , µPB... , uPC... , µPC... , uPD..., µPD... When indicating parts by reference number, please include the board name. The components identified by mark ! or dotted line with mark ! are critical for safety. Replace only with part number specified. Les composants identifiés par une marque ! sont critiques pour la sécurité. Ne les remplacer que par une pièce portant le numéro spécifié. Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks — 61 — SECTION 7 ELECTRICAL PARTS LIST * 1-670-391-11 AC POWER BOARD *************** * 1-533-213-31 HOLDER, FUSE < FUSE > !F001 1-576-106-11 FUSE 250V/3A < RESISTOR > !R001 1-202-727-00 CARBON 4.7M 5% 1/3W ************************************************************ * A-4414-924-A CD DECODER BOARD, COMPLETE *************************** < CAPACITOR > C02 1-126-963-11 ELECT 4.7uF 20% 50V C03 1-126-933-11 ELECT 100uF 20% 10V C04 1-162-306-11 CERAMIC 0.01uF 20% 16V C04A 1-164-159-11 CERAMIC 0.1uF 50V C05 1-136-159-00 FILM 0.033uF 5% 50V C06 1-162-306-11 CERAMIC 0.01uF 20% 16V C07 1-136-159-00 FILM 0.033uF 5% 50V C07A 1-162-199-31 CERAMIC 10PF 5% 50V C08 1-161-494-00 CERAMIC 0.022uF 25V C09 1-126-959-11 ELECT 0.47uF 20% 50V C10 1-162-306-11 CERAMIC 0.01uF 20% 16V C11 1-126-933-11 ELECT 100uF 20% 10V C11A 1-164-159-11 CERAMIC 0.1uF 50V C12 1-162-306-11 CERAMIC 0.01uF 20% 16V C13 1-164-159-11 CERAMIC 0.1uF 50V C14 1-162-302-11 CERAMIC 0.0022uF 30% 16V C15 1-164-159-11 CERAMIC 0.1uF 50V C16 1-136-159-00 FILM 0.033uF 5% 50V C17 1-136-165-00 FILM 0.1uF 5% 50V C18 1-164-159-11 CERAMIC 0.1uF 50V C19 1-126-963-11 ELECT 4.7uF 20% 50V C20 1-162-306-11 CERAMIC 0.01uF 20% 16V C21 1-136-157-00 FILM 0.022uF 5% 50V C22 1-126-933-11 ELECT 100uF 20% 10V C23 1-164-159-11 CERAMIC 0.1uF 50V C24 1-126-965-11 ELECT 22uF 20% 50V C25 1-126-960-11 ELECT 1uF 20% 50V C26 1-161-494-00 CERAMIC 0.022uF 25V C27 1-162-306-11 CERAMIC 0.01uF 20% 16V C28 1-164-159-11 CERAMIC 0.1uF 50V C30 1-126-933-11 ELECT 100uF 20% 10V C30A 1-164-159-11 CERAMIC 0.1uF 50V C31 1-162-600-11 CERAMIC 0.0047uF 30% 16V C32 1-162-301-11 CERAMIC 0.0015uF 30% 16V C33 1-162-306-11 CERAMIC 0.01uF 20% 16V C34 1-162-286-31 CERAMIC 220PF 10% 50V C35 1-162-306-11 CERAMIC 0.01uF 20% 16V C36 1-126-963-11 ELECT 4.7uF 20% 50V C37 1-164-159-11 CERAMIC 0.1uF 50V C37A 1-126-925-11 ELECT 470uF 20% 10V C38 1-102-958-00 CERAMIC 20PF 5% 50V C39 1-102-958-00 CERAMIC 20PF 5% 50V C41A 1-162-294-31 CERAMIC 0.001uF 10% 50V C42A 1-162-294-31 CERAMIC 0.001uF 10% 50V C44A 1-162-294-31 CERAMIC 0.001uF 10% 50V C45 1-126-934-11 ELECT 220uF 20% 10V C46 1-126-933-11 ELECT 100uF 20% 10V C51 1-162-288-31 CERAMIC 330PF 10% 50V C51A 1-126-959-11 ELECT 0.47uF 20% 50V C52 1-162-288-31 CERAMIC 330PF 10% 50V C53 1-162-284-31 CERAMIC 150PF 10% 50V C54 1-162-284-31 CERAMIC 150PF 10% 50V C55 1-162-284-31 CERAMIC 150PF 10% 50V C56 1-162-284-31 CERAMIC 150PF 10% 50V C57 1-126-961-11 ELECT 2.2uF 20% 50V C58 1-126-961-11 ELECT 2.2uF 20% 50V C59 1-162-294-31 CERAMIC 0.001uF 10% 50V C60 1-162-294-31 CERAMIC 0.001uF 10% 50V C81 1-164-159-11 CERAMIC 0.1uF 50V C83 1-164-159-11 CERAMIC 0.1uF 50V C84 1-162-282-31 CERAMIC 100PF 10% 50V C85 1-162-292-31 CERAMIC 680PF 10% 50V C86 1-162-282-31 CERAMIC 100PF 10% 50V C86A 1-161-494-00 CERAMIC 0.022uF 25V C87 1-162-282-31 CERAMIC 100PF 10% 50V C88 1-162-282-31 CERAMIC 100PF 10% 50V C90 1-161-494-00 CERAMIC 0.022uF 25V C90A 1-164-159-11 CERAMIC 0.1uF 50V C98 1-161-494-00 CERAMIC 0.022uF 25V < CONNECTOR > CN01 1-580-475-11 SOCKET, CONNECTOR 16P CN05 1-564-721-11 PIN, CONNECTOR (SMALL TYPE) 5P CN06 1-695-366-21 PIN, CONNECTOR (PC BOARD) 5P CN09 1-770-528-31 PIN, CONNECTOR (PC BOARD) 21P AC POWER CD DECODER • Abbreviation CND : Canadian AUS : Australian MX : Mexican SAF : South African www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks — 62 — < DIODE > D01 8-719-911-19 DIODE 1SS119-25 D04 8-719-921-41 DIODE 1SS133T D04A 8-719-991-33 DIODE 1SS176 < IC > IC01 8-752-069-56 IC CXA1782BQ IC02 8-759-388-27 IC TC9173P IC03 8-759-429-31 IC BA5941FP IC04 8-752-373-06 IC CXD2508AQ IC05 8-759-505-55 IC NJM4558L IC06 8-759-505-55 IC NJM4558L < COIL > L01 1-410-509-11 INDUCTOR 10uH < TRANSISTOR > Q01 8-729-195-23 TRANSISTOR 2SA952 Q02 8-729-195-23 TRANSISTOR 2SA952 Q04 8-729-194-57 TRANSISTOR 2SC945-P Q11 8-729-195-23 TRANSISTOR 2SA952 < RESISTOR > R01 1-249-459-11 CARBON 12K 5% 1/4W R02 1-249-430-11 CARBON 12K 5% 1/4W R03 1-249-397-11 CARBON 22 5% 1/4W F R04A 1-249-409-11 CARBON 220 5% 1/4W R05 1-247-863-11 CARBON 22K 5% 1/4W R06 1-247-847-11 CARBON 4.7K 5% 1/4W R07 1-249-430-11 CARBON 12K 5% 1/4W R07A 1-249-430-11 CARBON 12K 5% 1/4W R07B 1-249-430-11 CARBON 12K 5% 1/4W R08 1-249-460-11 CARBON 15K 5% 1/4W R09 1-249-460-11 CARBON 15K 5% 1/4W R09A 1-247-847-11 CARBON 4.7K 5% 1/4W R10 1-247-718-11 CARBON 2.7K 5% 1/4W F R11 1-249-438-11 CARBON 56K 5% 1/4W R12 1-247-879-11 CARBON 100K 5% 1/4W R13 1-247-896-11 CARBON 510K 5% 1/4W R13A 1-247-861-11 CARBON 18K 5% 1/4W R14 1-247-879-11 CARBON 100K 5% 1/4W R14A 1-247-861-11 CARBON 18K 5% 1/4W R15 1-247-881-00 CARBON 120K 5% 1/4W R16 1-247-887-00 CARBON 220K 5% 1/4W R17 1-247-879-11 CARBON 100K 5% 1/4W R18 1-249-428-11 CARBON 8.2K 5% 1/4W F R19 1-249-431-11 CARBON 15K 5% 1/4W R21 1-247-863-11 CARBON 22K 5% 1/4W R22 1-247-879-11 CARBON 100K 5% 1/4W R23 1-249-430-11 CARBON 12K 5% 1/4W R24 1-247-883-00 CARBON 150K 5% 1/4W R25 1-247-879-11 CARBON 100K 5% 1/4W R26 1-247-855-11 CARBON 10K 5% 1/4W R27 1-249-430-11 CARBON 12K 5% 1/4W R28 1-247-855-11 CARBON 10K 5% 1/4W R29 1-247-843-11 CARBON 3.3K 5% 1/4W R30 1-247-843-11 CARBON 3.3K 5% 1/4W R31 1-247-855-11 CARBON 10K 5% 1/4W R32 1-247-903-00 CARBON 1M 5% 1/4W R33 1-247-855-11 CARBON 10K 5% 1/4W R34 1-247-879-11 CARBON 100K 5% 1/4W R35 1-247-847-11 CARBON 4.7K 5% 1/4W R36 1-247-847-11 CARBON 4.7K 5% 1/4W R37 1-247-807-11 CARBON 100 5% 1/4W R38 1-247-807-11 CARBON 100 5% 1/4W R39 1-247-847-11 CARBON 4.7K 5% 1/4W R41 1-247-807-11 CARBON 100 5% 1/4W R42 1-247-807-11 CARBON 100 5% 1/4W R44 1-247-807-11 CARBON 100 5% 1/4W R50 1-247-847-11 CARBON 4.7K 5% 1/4W R52 1-247-721-11 CARBON 4.7K 5% 1/4W F R53 1-249-411-11 CARBON 330 5% 1/4W R56 1-247-847-11 CARBON 4.7K 5% 1/4W R57 1-249-427-11 CARBON 6.8K 5% 1/4W F R58 1-249-442-11 CARBON 510 5% 1/4W R59 1-247-903-00 CARBON 1M 5% 1/4W R61 1-247-855-11 CARBON 10K 5% 1/4W R62 1-247-855-11 CARBON 10K 5% 1/4W R63 1-247-855-11 CARBON 10K 5% 1/4W R64 1-247-855-11 CARBON 10K 5% 1/4W R65 1-247-864-11 CARBON 24K 5% 1/4W R66 1-247-864-11 CARBON 24K 5% 1/4W R67 1-247-864-11 CARBON 24K 5% 1/4W R68 1-247-864-11 CARBON 24K 5% 1/4W R69 1-249-430-11 CARBON 12K 5% 1/4W R70 1-249-430-11 CARBON 12K 5% 1/4W R71 1-249-430-11 CARBON 12K 5% 1/4W R72 1-249-430-11 CARBON 12K 5% 1/4W R73 1-247-839-11 CARBON 2.2K 5% 1/4W R74 1-247-839-11 CARBON 2.2K 5% 1/4W R75 1-247-847-11 CARBON 4.7K 5% 1/4W R76 1-247-847-11 CARBON 4.7K 5% 1/4W R79 1-249-405-11 CARBON 100 5% 1/4W F R80 1-247-883-00 CARBON 150K 5% 1/4W R81 1-247-807-11 CARBON 100 5% 1/4W R82 1-247-807-11 CARBON 100 5% 1/4W R83 1-249-469-11 CARBON 100K 5% 1/4W R84 1-249-465-11 CARBON 47K 5% 1/4W R85 1-249-465-11 CARBON 47K 5% 1/4W R86 1-249-465-11 CARBON 47K 5% 1/4W R87 1-249-465-11 CARBON 47K 5% 1/4W R88 1-249-469-11 CARBON 100K 5% 1/4W R89 1-247-839-11 CARBON 2.2K 5% 1/4W R90 1-247-839-11 CARBON 2.2K 5% 1/4W R90B 1-247-831-11 CARBON 1K 5% 1/4W R91 1-247-839-11 CARBON 2.2K 5% 1/4W R92 1-247-839-11 CARBON 2.2K 5% 1/4W R93 1-249-420-11 CARBON 1.8K 5% 1/4W F R94 1-249-420-11 CARBON 1.8K 5% 1/4W F < VARIABLE RESISTOR > VR01 1-228-996-00 RES, ADJ, METAL 47K VR02 1-228-998-00 RES, ADJ, METAL 220K < CRYSTAL > XTL01 1-760-123-11 VIBRATOR, CRYSTAL 33.8688MHz ************************************************************ CD DECODER www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks — 63 — * 1-670-387-11 DISK BOARD ********** < RESISTOR > R630 1-247-841-11 CARBON 2.7K 5% 1/4W R631 1-249-424-11 CARBON 3.9K 5% 1/4W F R632 1-249-427-11 CARBON 6.8K 5% 1/4W F R633 1-249-431-11 CARBON 15K 5% 1/4W R634 1-249-436-11 CARBON 39K 5% 1/4W < SWITCH > S619 1-572-674-11 SWITCH, PUSH (DISC 1) S620 1-572-674-11 SWITCH, PUSH (DISC 2) S621 1-572-674-11 SWITCH, PUSH (DISC 3) S622 1-572-674-11 SWITCH, PUSH (DISC SKIP) S623 1-572-674-11 SWITCH, PUSH (OPEN/CLOSE) ************************************************************ * 1-670-392-11 H.P BOARD ********* < JACK > JK303 1-785-050-11 JACK (LARGE TYPE)(PHONE) ************************************************************ * A-4405-471-A MAIN BOARD, COMPLETE ********************* * 1-533-213-31 HOLDER, FUSE < CAPACITOR > C101 1-162-294-31 CERAMIC 0.001uF 10% 50V C102 1-162-294-31 CERAMIC 0.001uF 10% 50V C103 1-162-193-31 CERAMIC 3.3PF 10% 50V C104 1-161-494-00 CERAMIC 0.022uF 25V C105 1-162-206-31 CERAMIC 20PF 5% 50V C106 1-161-494-00 CERAMIC 0.022uF 25V C107 1-161-494-00 CERAMIC 0.022uF 25V C108 1-126-933-11 ELECT 100uF 20% 16V C109 1-162-191-31 CERAMIC 2.2PF 10% 50V C110 1-162-191-31 CERAMIC 2.2PF 10% 50V C111 1-162-217-31 CERAMIC 56PF 5% 50V C112 1-162-282-31 CERAMIC 100PF 10% 50V C114 1-164-159-11 CERAMIC 0.1uF 50V C115 1-162-294-31 CERAMIC 0.001uF 10% 50V C116 1-130-014-00 FILM 470PF 5% 50V C117 1-162-203-31 CERAMIC 15PF 5% 50V C118 1-126-933-11 ELECT 100uF 20% 16V C119 1-161-494-00 CERAMIC 0.022uF 25V C120 1-161-494-00 CERAMIC 0.022uF 25V C121 1-162-203-31 CERAMIC 15PF 5% 50V C122 1-126-961-11 ELECT 2.2uF 20% 50V C123 1-126-960-11 ELECT 1uF 20% 50V C124 1-162-206-31 CERAMIC 20PF 5% 50V C125 1-126-960-11 ELECT 1uF 20% 50V C126 1-110-671-31 CERAMIC 47000PF 50V C127 1-126-964-11 ELECT 10uF 20% 50V C128 1-161-494-00 CERAMIC 0.022uF 25V C129 1-109-889-11 ELECT 1uF 20% 50V C130 1-161-054-00 CERAMIC 0.018uF 10% 25V C131 1-161-054-00 CERAMIC 0.018uF 10% 25V C132 1-161-047-00 CERAMIC 0.0047uF 10% 50V C133 1-161-047-00 CERAMIC 0.0047uF 10% 50V C134 1-162-294-31 CERAMIC 0.001uF 10% 50V C135 1-126-962-11 ELECT 3.3uF 20% 50V C137 1-126-959-11 ELECT 0.47uF 20% 50V C138 1-161-494-00 CERAMIC 0.022uF 25V C139 1-161-494-00 CERAMIC 0.022uF 25V C140 1-126-933-11 ELECT 100uF 20% 16V C141 1-161-494-00 CERAMIC 0.022uF 25V C142 1-126-933-11 ELECT 100uF 20% 16V C143 1-126-959-11 ELECT 0.47uF 20% 50V C144 1-161-494-00 CERAMIC 0.022uF 25V C145 1-162-217-31 CERAMIC 56PF 5% 50V C146 1-162-294-31 CERAMIC 0.001uF 10% 50V C148 1-161-494-00 CERAMIC 0.022uF 25V C149 1-162-282-31 CERAMIC 100PF 10% 50V C150 1-164-159-11 CERAMIC 0.1uF 50V C151 1-128-551-11 ELECT 22uF 20% 25V C152 1-162-282-31 CERAMIC 100PF 10% 50V C154 1-162-282-31 CERAMIC 100PF 10% 50V C155 1-162-282-31 CERAMIC 100PF 10% 50V C156 1-102-516-11 CERAMIC 27PF 5% 50V C157 1-102-516-11 CERAMIC 27PF 5% 50V C158 1-126-967-11 ELECT 47uF 20% 16V C159 1-162-282-31 CERAMIC 100PF 10% 50V C160 1-126-963-11 ELECT 4.7uF 20% 50V C161 1-126-963-11 ELECT 4.7uF 20% 50V C162 1-161-494-00 CERAMIC 0.022uF 25V C163 1-161-494-00 CERAMIC 0.022uF 25V C164 1-162-282-31 CERAMIC 100PF 10% 50V C165 1-161-494-00 CERAMIC 0.022uF 25V C168 1-162-199-31 CERAMIC 10PF 5% 50V C201 1-162-286-31 CERAMIC 220PF 10% 50V C202 1-162-286-31 CERAMIC 220PF 10% 50V C203 1-162-292-31 CERAMIC 680PF 10% 50V C204 1-162-292-31 CERAMIC 680PF 10% 50V C205 1-162-286-31 CERAMIC 220PF 10% 50V C206 1-162-286-31 CERAMIC 220PF 10% 50V C207 1-126-967-11 ELECT 47uF 20% 16V C208 1-126-967-11 ELECT 47uF 20% 16V C209 1-161-052-00 CERAMIC 0.012uF 10% 25V C210 1-161-052-00 CERAMIC 0.012uF 10% 25V C211 1-126-960-11 ELECT 1uF 20% 50V C212 1-126-960-11 ELECT 1uF 20% 50V C213 1-162-294-31 CERAMIC 0.001uF 10% 50V C214 1-162-294-31 CERAMIC 0.001uF 10% 50V C215 1-130-472-00 MYLAR 0.0012uF 5% 50V C216 1-130-472-00 MYLAR 0.0012uF 5% 50V C217 1-162-286-31 CERAMIC 220PF 10% 50V C218 1-162-286-31 CERAMIC 220PF 10% 50V C219 1-126-962-11 ELECT 3.3uF 20% 50V C220 1-126-962-11 ELECT 3.3uF 20% 50V C221 1-126-967-11 ELECT 47uF 20% 16V C222 1-126-967-11 ELECT 47uF 20% 16V C223 1-162-294-31 CERAMIC 0.001uF 10% 50V DISK H.P MAIN www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks — 64 — C224 1-162-294-31 CERAMIC 0.001uF 10% 50V C225 1-126-962-11 ELECT 3.3uF 20% 50V C226 1-126-962-11 ELECT 3.3uF 20% 50V C228 1-126-964-11 ELECT 10uF 20% 50V C230 1-130-485-00 MYLAR 0.015uF 5% 50V C231 1-130-483-00 MYLAR 0.01uF 5% 50V C232 1-162-600-11 CERAMIC 0.0047uF 30% 16V C233 1-130-992-11 FILM 0.022uF 5% 50V C234 1-126-967-11 ELECT 47uF 20% 16V C235 1-161-494-00 CERAMIC 0.022uF 25V C237 1-126-924-11 ELECT 330uF 20% 10V C238 1-126-962-11 ELECT 3.3uF 20% 50V C239 1-162-292-31 CERAMIC 680PF 10% 50V C240 1-162-292-31 CERAMIC 680PF 10% 50V C241 1-126-967-11 ELECT 47uF 20% 16V C243 1-126-961-11 ELECT 2.2uF 20% 50V C303 1-126-959-11 ELECT 0.47uF 20% 50V C304 1-126-959-11 ELECT 0.47uF 20% 50V C305 1-126-959-11 ELECT 0.47uF 20% 50V C306 1-126-959-11 ELECT 0.47uF 20% 50V C307 1-126-959-11 ELECT 0.47uF 20% 50V C308 1-126-959-11 ELECT 0.47uF 20% 50V C309 1-162-199-31 CERAMIC 10PF 5% 50V C310 1-162-199-31 CERAMIC 10PF 5% 50V C317 1-130-471-00 MYLAR 0.001uF 5% 50V C318 1-130-471-00 MYLAR 0.001uF 5% 50V C319 1-130-485-00 MYLAR 0.015uF 5% 50V C320 1-130-485-00 MYLAR 0.015uF 5% 50V C321 1-162-290-31 CERAMIC 470PF 10% 50V C322 1-162-290-31 CERAMIC 470PF 10% 50V C323 1-162-203-31 CERAMIC 15PF 5% 50V C324 1-162-203-31 CERAMIC 15PF 5% 50V C325 1-130-485-00 MYLAR 0.015uF 5% 50V C326 1-130-485-00 MYLAR 0.015uF 5% 50V C327 1-126-934-11 ELECT 220uF 20% 16V C328 1-126-934-11 ELECT 220uF 20% 16V C329 1-162-199-31 CERAMIC 10PF 5% 50V C330 1-162-199-31 CERAMIC 10PF 5% 50V C333 1-126-933-11 ELECT 100uF 20% 16V C334 1-126-960-11 ELECT 1uF 20% 50V C335 1-126-960-11 ELECT 1uF 20% 50V C337 1-126-959-11 ELECT 0.47uF 20% 50V C338 1-126-959-11 ELECT 0.47uF 20% 50V C341 1-162-215-31 CERAMIC 47PF 5% 50V C342 1-162-215-31 CERAMIC 47PF 5% 50V C343 1-162-282-31 CERAMIC 100PF 10% 50V C344 1-162-282-31 CERAMIC 100PF 10% 50V C347 1-126-933-11 ELECT 100uF 20% 16V C348 1-126-961-11 ELECT 2.2uF 20% 50V C349 1-126-961-11 ELECT 2.2uF 20% 50V C350 1-126-964-11 ELECT 10uF 20% 50V C352 1-126-964-11 ELECT 10uF 20% 50V C353 1-126-964-11 ELECT 10uF 20% 50V C355 1-126-964-11 ELECT 10uF 20% 50V C356 1-126-933-11 ELECT 100uF 20% 16V C357 1-162-282-31 CERAMIC 100PF 10% 50V C358 1-162-282-31 CERAMIC 100PF 10% 50V C359 1-164-159-11 CERAMIC 0.1uF 50V C360 1-164-159-11 CERAMIC 0.1uF 50V C361 1-130-485-00 MYLAR 0.015uF 5% 50V C362 1-130-485-00 MYLAR 0.015uF 5% 50V C363 1-162-284-31 CERAMIC 150PF 10% 50V C364 1-162-284-31 CERAMIC 150PF 10% 50V C365 1-130-481-00 MYLAR 0.0068uF 5% 50V C366 1-130-481-00 MYLAR 0.0068uF 5% 50V C370 1-109-953-11 ELECT 2.2uF 20% 50V C373 1-162-286-31 CERAMIC 220PF 10% 50V C374 1-162-286-31 CERAMIC 220PF 10% 50V C375 1-162-286-31 CERAMIC 220PF 10% 50V C376 1-126-964-11 ELECT 10uF 20% 50V C401 1-126-974-11 ELECT 3300uF 20% 50V C402 1-126-974-11 ELECT 3300uF 20% 50V C403 1-126-969-11 ELECT 220uF 20% 50V C404 1-126-967-11 ELECT 47uF 20% 16V C405 1-161-494-00 CERAMIC 0.022uF 25V C406 1-161-494-00 CERAMIC 0.022uF 25V C407 1-161-494-00 CERAMIC 0.022uF 25V C408 1-161-494-00 CERAMIC 0.022uF 25V C409 1-161-494-00 CERAMIC 0.022uF 25V C410 1-126-943-11 ELECT 2200uF 20% 25V C411 1-130-483-00 MYLAR 0.01uF 5% 50V C412 1-126-933-11 ELECT 100uF 20% 16V C413 1-130-483-00 MYLAR 0.01uF 5% 50V C414 1-161-494-00 CERAMIC 0.022uF 25V C415 1-161-494-00 CERAMIC 0.022uF 25V C416 1-126-933-11 ELECT 100uF 20% 16V C417 1-126-933-11 ELECT 100uF 20% 16V C418 1-126-935-11 ELECT 470uF 20% 16V C419 1-161-494-00 CERAMIC 0.022uF 25V C420 1-126-933-11 ELECT 100uF 20% 16V C421 1-161-494-00 CERAMIC 0.022uF 25V C422 1-126-935-11 ELECT 470uF 20% 16V C423 1-161-494-00 CERAMIC 0.022uF 25V C424 1-130-483-00 MYLAR 0.01uF 5% 50V C425 1-130-483-00 MYLAR 0.01uF 5% 50V C426 1-126-933-11 ELECT 100uF 20% 16V C427 1-161-494-00 CERAMIC 0.022uF 25V C428 1-126-933-11 ELECT 100uF 20% 16V C430 1-126-969-11 ELECT 220uF 20% 50V C431 1-128-553-11 ELECT 220uF 20% 63V C434 1-126-933-11 ELECT 100uF 20% 16V C442 1-161-494-00 CERAMIC 0.022uF 25V C443 1-161-494-00 CERAMIC 0.022uF 25V C444 1-126-934-11 ELECT 220uF 20% 16V C445 1-126-968-11 ELECT 100uF 20% 50V C455 1-126-960-11 ELECT 1uF 20% 50V C501 1-162-294-31 CERAMIC 0.001uF 10% 50V C502 1-162-294-31 CERAMIC 0.001uF 10% 50V C503 1-162-600-11 CERAMIC 0.0047uF 30% 16V C504 1-162-600-11 CERAMIC 0.0047uF 30% 16V MAIN www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks — 65 — C505 1-126-964-11 ELECT 10uF 20% 50V C506 1-126-964-11 ELECT 10uF 20% 50V C507 1-126-968-11 ELECT 100uF 20% 50V C508 1-126-964-11 ELECT 10uF 20% 50V C509 1-126-964-11 ELECT 10uF 20% 50V C510 1-164-159-11 CERAMIC 0.1uF 50V C511 1-162-195-31 CERAMIC 4.7PF 10% 50V C512 1-162-195-31 CERAMIC 4.7PF 10% 50V C513 1-130-495-00 MYLAR 0.1uF 5% 50V C514 1-130-495-00 MYLAR 0.1uF 5% 50V C515 1-126-968-11 ELECT 100uF 20% 50V C516 1-164-159-11 CERAMIC 0.1uF 50V C517 1-126-933-11 ELECT 100uF 20% 16V C518 1-161-379-00 CERAMIC 0.01uF 20% 25V C519 1-161-379-00 CERAMIC 0.01uF 20% 25V C520 1-130-495-00 MYLAR 0.1uF 5% 50V C521 1-130-495-00 MYLAR 0.1uF 5% 50V C551 1-161-494-00 CERAMIC 0.022uF 25V C552 1-161-494-00 CERAMIC 0.022uF 25V C553 1-126-960-11 ELECT 1uF 20% 50V C554 1-161-379-00 CERAMIC 0.01uF 20% 25V C555 1-126-933-11 ELECT 100uF 20% 16V C556 1-161-494-00 CERAMIC 0.022uF 25V C557 1-126-963-11 ELECT 4.7uF 20% 50V C558 1-126-933-11 ELECT 100uF 20% 16V C581 1-126-967-11 ELECT 47uF 20% 16V < FILTER > CF101 1-579-568-11 FILTER, CERAMIC CF102 1-567-390-11 FILTER,CERAMIC 10.7M CF103 1-527-996-11 FILTER, CERAMIC CF104 1-579-856-11 DISCRIMINATOR, CERAMIC CF105 1-577-091-11 OSCILLATOR, CERAMIC < CONNECTOR > * CN201 1-564-705-11 PIN, CONNECTOR (SMALL TYPE) 3P CN202 1-564-707-11 PIN, CONNECTOR (SMALL TYPE) 5P * CN203 1-564-704-11 PIN, CONNECTOR (SMALL TYPE) 2P * CN204 1-568-273-11 SOCKET, CONNECTOR 7P * CN301 1-770-334-11 PIN, CONNECTOR (PC BOARD) 17P * CN302 1-568-272-11 SOCKET, CONNECTOR 6P CN401 1-564-511-11 PLUG, CONNECTOR 8P < DIODE > D101 8-719-059-68 DIODE KV1340A-2 D102 8-719-991-33 DIODE 1SS133T-77 D103 8-719-059-68 DIODE KV1340A-2 D104 8-719-800-72 DIODE 1SV149-B D105 8-719-991-33 DIODE 1SS133T-77 D106 8-719-991-33 DIODE 1SS133T-77 D107 8-719-109-89 DIODE RD5.6ESB2 D108 8-719-991-33 DIODE 1SS133T-77 D109 8-719-991-33 DIODE 1SS133T-77 D110 8-719-991-33 DIODE 1SS133T-77 D201 8-719-991-33 DIODE 1SS133T-77 D202 8-719-991-33 DIODE 1SS133T-77 D203 8-719-991-33 DIODE 1SS133T-77 D204 8-719-991-33 DIODE 1SS133T-77 D205 8-719-991-33 DIODE 1SS133T-77 D208 8-719-991-33 DIODE 1SS133T-77 D209 8-719-991-33 DIODE 1SS133T-77 D210 8-719-991-33 DIODE 1SS133T-77 D211 8-719-991-33 DIODE 1SS133T-77 D212 8-719-991-33 DIODE 1SS133T-77 D301 8-719-991-33 DIODE 1SS133T-77 D401 DIODE GBU4D D402 8-719-921-40 DIODE MTZJ-4.7C D405 8-719-200-02 DIODE 10E2 D406 8-719-200-02 DIODE 10E2 D407 8-719-200-02 DIODE 10E2 D408 8-719-200-02 DIODE 10E2 D409 8-719-110-31 DIODE RD12ES-B2 D411 8-719-110-31 DIODE RD12ES-B2 D412 8-719-110-08 DIODE RD8.2ES-B2 D413 8-719-109-93 DIODE RD6.2ESB2 D414 8-719-200-02 DIODE 10E2 D415 8-719-200-02 DIODE 10E2 D416 8-719-200-02 DIODE 10E2 D417 8-719-991-33 DIODE 1SS133T-77 D441 8-719-982-13 DIODE MTZJ-27 D501 8-719-991-33 DIODE 1SS133T-77 D551 8-719-991-33 DIODE 1SS133T-77 D552 8-719-991-33 DIODE 1SS133T-77 D553 8-719-991-33 DIODE 1SS133T-77 D581 8-719-991-33 DIODE 1SS133T-77 D584 8-719-991-33 DIODE 1SS133T-77 < FUSE > !F401 1-576-104-11 FUSE 250V/2A < IC > IC101 8-759-505-55 IC NJM4558L IC102 8-759-090-40 IC LA1831 IC103 8-759-175-87 IC LC7218-ST IC201 8-759-242-58 IC TA8189N IC301 8-759-473-59 IC LC75392 IC302 8-759-505-55 IC NJM4558L IC501 8-749-013-04 IC PHOTO COUPLER MOC8104TV IC502 8-759-111-68 IC uPC1237HA < TERMINAL > JK101 1-694-092-21 TERMINAL BOARD (SPEAKER) JK501 1-694-092-21 TERMINAL BOARD (SPEAKER) < COIL > L101 1-429-551-11 TRANSFORMER, FM RF L102 1-429-550-11 TRANSFORMER, FM ANT L103 1-411-798-11 COIL, FM OSC L104 1-411-901-11 COIL, ANTENNA L105 1-429-555-11 TRANSFORMER, MW OSC L106 1-408-611-31 INDUCTOR 47mH L201 1-429-552-11 TRANSFORMER, BIAS OSCILLATION * L501 1-420-872-00 COIL, AIR CORE * L502 1-420-872-00 COIL, AIR CORE MAIN The components identified by mark ! or dotted line with mark ! are critical for safety. Replace only with part number specified. Les composants identifiés par une marque ! sont critiques pour la sécurité. Ne les remplacer que par une pièce portant le numéro spécifié. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks — 66 — < TRANSISTOR > Q101 8-729-672-42 TRANSISTOR 2SC2724-C Q102 8-729-178-63 TRANSISTOR 2SC2786-K Q103 8-729-119-76 TRANSISTOR 2SA1175-HFE Q104 8-729-041-83 TRANSISTOR 2SK544E Q105 8-729-194-57 TRANSISTOR 2SC945-P Q106 8-729-194-57 TRANSISTOR 2SC945-P Q108 8-729-194-57 TRANSISTOR 2SC945-P Q109 8-729-194-57 TRANSISTOR 2SC945-P Q201 8-729-194-57 TRANSISTOR 2SC945-P Q202 8-729-194-57 TRANSISTOR 2SC945-P Q203 8-729-194-57 TRANSISTOR 2SC945-P Q204 8-729-194-57 TRANSISTOR 2SC945-P Q205 8-729-194-57 TRANSISTOR 2SC945-P Q206 8-729-194-57 TRANSISTOR 2SC945-P Q207 8-729-119-76 TRANSISTOR 2SA1175-HFE Q208 8-729-194-57 TRANSISTOR 2SC945-P Q209 8-729-194-57 TRANSISTOR 2SC945-P Q210 8-729-194-57 TRANSISTOR 2SC945-P Q211 8-729-194-57 TRANSISTOR 2SC945-P Q212 8-729-194-57 TRANSISTOR 2SC945-P Q213 8-729-119-76 TRANSISTOR 2SA1175-HFE Q214 8-729-194-57 TRANSISTOR 2SC945-P Q216 8-729-119-76 TRANSISTOR 2SA1175-HFE Q217 8-729-119-76 TRANSISTOR 2SA1175-HFE Q218 8-729-142-46 TRANSISTOR 2SC2001-LK Q220 8-729-194-57 TRANSISTOR 2SC945-P Q301 8-729-194-57 TRANSISTOR 2SC945-P Q302 8-729-194-57 TRANSISTOR 2SC945-P Q303 8-729-231-55 TRANSISTOR 2SC2878-AB Q304 8-729-231-55 TRANSISTOR 2SC2878-AB Q306 8-729-194-57 TRANSISTOR 2SC945-P Q307 8-729-194-57 TRANSISTOR 2SC945-P Q311 8-729-194-57 TRANSISTOR 2SC945-P Q312 8-729-194-57 TRANSISTOR 2SC945-P Q401 8-729-188-23 TRANSISTOR 2SD882-P Q402 8-729-142-46 TRANSISTOR 2SC2001-LK Q403 8-729-188-23 TRANSISTOR 2SD882-P Q404 8-729-142-46 TRANSISTOR 2SC2001-LK Q406 8-729-993-43 TRANSISTOR 2SA934R Q407 8-729-194-57 TRANSISTOR 2SC945-P Q408 8-729-232-32 TRANSISTOR 2SA965-OY-TPE6 Q409 8-729-029-86 TRANSISTOR DTC124ES Q410 8-729-029-86 TRANSISTOR DTC124ES Q551 8-729-184-53 TRANSISTOR 2SC1845-EA Q552 8-729-184-53 TRANSISTOR 2SC1845-EA Q553 8-729-140-82 TRANSISTOR 2SA988-PAFAEA Q583 8-729-029-66 TRANSISTOR DTC114ESA Q584 8-729-119-76 TRANSISTOR 2SA1175-HFE Q585 8-729-029-86 TRANSISTOR DTC124ES Q586 8-729-029-86 TRANSISTOR DTC124ES < RESISTOR > R101 1-247-879-11 CARBON 100K 5% 1/4W R102 1-247-830-11 CARBON 910 5% 1/4W R103 1-249-398-11 CARBON 27 5% 1/4W F R104 1-247-807-11 CARBON 100 5% 1/4W R105 1-249-411-11 CARBON 330 5% 1/4W R106 1-247-807-11 CARBON 100 5% 1/4W R107 1-247-879-11 CARBON 100K 5% 1/4W R108 1-247-871-11 CARBON 47K 5% 1/4W R109 1-247-879-11 CARBON 100K 5% 1/4W R110 1-247-867-11 CARBON 33K 5% 1/4W R111 1-247-830-11 CARBON 910 5% 1/4W R112 1-247-807-11 CARBON 100 5% 1/4W R113 1-247-879-11 CARBON 100K 5% 1/4W R114 1-247-879-11 CARBON 100K 5% 1/4W R115 1-247-830-11 CARBON 910 5% 1/4W R116 1-249-397-11 CARBON 22 5% 1/4W F R117 1-249-431-11 CARBON 15K 5% 1/4W R118 1-247-807-11 CARBON 100 5% 1/4W R119 1-249-413-11 CARBON 470 5% 1/4W F R120 1-247-843-11 CARBON 3.3K 5% 1/4W R121 1-247-843-11 CARBON 3.3K 5% 1/4W R122 1-249-409-11 CARBON 220 5% 1/4W F R123 1-249-428-11 CARBON 8.2K 5% 1/4W F R124 1-247-843-11 CARBON 3.3K 5% 1/4W R126 1-247-843-11 CARBON 3.3K 5% 1/4W R127 1-247-843-11 CARBON 3.3K 5% 1/4W R128 1-247-847-11 CARBON 4.7K 5% 1/4W R129 1-247-847-11 CARBON 4.7K 5% 1/4W R130 1-247-807-11 CARBON 100 5% 1/4W R131 1-247-830-11 CARBON 910 5% 1/4W R132 1-247-855-11 CARBON 10K 5% 1/4W R133 1-247-843-11 CARBON 3.3K 5% 1/4W R134 1-249-427-11 CARBON 6.8K 5% 1/4W F R135 1-247-830-11 CARBON 910 5% 1/4W R136 1-247-847-11 CARBON 4.7K 5% 1/4W R137 1-247-855-11 CARBON 10K 5% 1/4W R138 1-247-807-11 CARBON 100 5% 1/4W R139 1-247-855-11 CARBON 10K 5% 1/4W R140 1-247-855-11 CARBON 10K 5% 1/4W R141 1-247-839-11 CARBON 2.2K 5% 1/4W R142 1-247-839-11 CARBON 2.2K 5% 1/4W R143 1-247-839-11 CARBON 2.2K 5% 1/4W R146 1-247-830-11 CARBON 910 5% 1/4W R148 1-247-855-11 CARBON 10K 5% 1/4W R149 1-247-855-11 CARBON 10K 5% 1/4W R150 1-247-843-11 CARBON 3.3K 5% 1/4W R160 1-247-903-00 CARBON 1M 5% 1/4W R201 1-249-393-11 CARBON 10 5% 1/4W F R202 1-249-393-11 CARBON 10 5% 1/4W F R203 1-247-889-00 CARBON 270K 5% 1/4W R204 1-247-889-00 CARBON 270K 5% 1/4W R205 1-249-406-11 CARBON 120 5% 1/4W F R205A 1-247-827-11 CARBON 680 5% 1/4W R206 1-249-406-11 CARBON 120 5% 1/4W F R206A 1-247-827-11 CARBON 680 5% 1/4W R207 1-249-430-11 CARBON 12K 5% 1/4W R208 1-249-430-11 CARBON 12K 5% 1/4W R209 1-247-863-11 CARBON 22K 5% 1/4W R210 1-247-855-11 CARBON 10K 5% 1/4W R211 1-247-891-00 CARBON 330K 5% 1/4W R212 1-247-891-00 CARBON 330K 5% 1/4W R213 1-247-847-11 CARBON 4.7K 5% 1/4W R214 1-247-847-11 CARBON 4.7K 5% 1/4W R215 1-247-855-11 CARBON 10K 5% 1/4W R216 1-249-431-11 CARBON 15K 5% 1/4W MAIN www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks — 67 — R217 1-247-871-11 CARBON 47K 5% 1/4W R218 1-249-409-11 CARBON 220 5% 1/4W F R219 1-247-841-11 CARBON 2.7K 5% 1/4W R220 1-249-434-11 CARBON 27K 5% 1/4W R221 1-247-879-11 CARBON 100K 5% 1/4W R222 1-247-879-11 CARBON 100K 5% 1/4W R223 1-247-855-11 CARBON 10K 5% 1/4W R224 1-247-855-11 CARBON 10K 5% 1/4W R225 1-249-434-11 CARBON 27K 5% 1/4W R226 1-249-434-11 CARBON 27K 5% 1/4W R227 1-247-885-00 CARBON 180K 5% 1/4W R228 1-247-885-00 CARBON 180K 5% 1/4W R229 1-247-881-00 CARBON 120K 5% 1/4W R230 1-247-881-00 CARBON 120K 5% 1/4W R231 1-249-420-11 CARBON 1.8K 5% 1/4W F R232 1-249-420-11 CARBON 1.8K 5% 1/4W F R233 1-247-839-11 CARBON 2.2K 5% 1/4W R234 1-247-839-11 CARBON 2.2K 5% 1/4W R235 1-247-855-11 CARBON 10K 5% 1/4W R236 1-247-855-11 CARBON 10K 5% 1/4W R237 1-247-839-11 CARBON 2.2K 5% 1/4W R238 1-247-843-11 CARBON 3.3K 5% 1/4W R240 1-249-393-11 CARBON 10 5% 1/4W F R241 1-249-434-11 CARBON 27K 5% 1/4W R242 1-249-413-11 CARBON 470 5% 1/4W F R243 1-247-855-11 CARBON 10K 5% 1/4W R244 1-247-855-11 CARBON 10K 5% 1/4W R245 1-249-393-11 CARBON 10 5% 1/4W F R246 1-249-393-11 CARBON 10 5% 1/4W F R247 1-247-855-11 CARBON 10K 5% 1/4W R248 1-249-434-11 CARBON 27K 5% 1/4W R249 1-249-381-11 CARBON 1 5% 1/4W F R250 1-247-847-11 CARBON 4.7K 5% 1/4W R251 1-247-847-11 CARBON 4.7K 5% 1/4W R252 1-247-871-11 CARBON 47K 5% 1/4W R253 1-247-871-11 CARBON 47K 5% 1/4W R256 1-247-831-11 CARBON 1K 5% 1/4W R257 1-247-839-11 CARBON 2.2K 5% 1/4W R258 1-249-431-11 CARBON 15K 5% 1/4W R259 1-247-871-11 CARBON 47K 5% 1/4W R261 1-247-839-11 CARBON 2.2K 5% 1/4W R264 1-247-871-11 CARBON 47K 5% 1/4W R265 1-247-887-00 CARBON 220K 5% 1/4W R266 1-247-839-11 CARBON 2.2K 5% 1/4W R267 1-247-871-11 CARBON 47K 5% 1/4W R268 1-247-871-11 CARBON 47K 5% 1/4W R269 1-247-891-00 CARBON 330K 5% 1/4W R270 1-247-891-00 CARBON 330K 5% 1/4W R271 1-247-839-11 CARBON 2.2K 5% 1/4W R301 1-247-855-11 CARBON 10K 5% 1/4W R302 1-247-855-11 CARBON 10K 5% 1/4W R305 1-249-417-11 CARBON 1K 5% 1/4W F R306 1-249-417-11 CARBON 1K 5% 1/4W F R307 1-249-418-11 CARBON 1.2K 5% 1/4W F R308 1-249-418-11 CARBON 1.2K 5% 1/4W F R309 1-249-440-11 CARBON 82K 5% 1/4W R310 1-249-440-11 CARBON 82K 5% 1/4W R315 1-247-867-11 CARBON 33K 5% 1/4W R316 1-247-867-11 CARBON 33K 5% 1/4W R317 1-247-887-00 CARBON 220K 5% 1/4W R318 1-247-887-00 CARBON 220K 5% 1/4W R319 1-247-855-11 CARBON 10K 5% 1/4W R320 1-247-855-11 CARBON 10K 5% 1/4W R321 1-249-434-11 CARBON 27K 5% 1/4W R322 1-249-434-11 CARBON 27K 5% 1/4W R323 1-247-871-11 CARBON 47K 5% 1/4W R324 1-247-871-11 CARBON 47K 5% 1/4W R325 1-247-863-11 CARBON 22K 5% 1/4W R326 1-247-863-11 CARBON 22K 5% 1/4W R327 1-249-434-11 CARBON 27K 5% 1/4W R328 1-249-434-11 CARBON 27K 5% 1/4W R329 1-249-430-11 CARBON 12K 5% 1/4W R330 1-249-430-11 CARBON 12K 5% 1/4W R331 1-247-839-11 CARBON 2.2K 5% 1/4W R332 1-247-839-11 CARBON 2.2K 5% 1/4W R333 1-247-839-11 CARBON 2.2K 5% 1/4W R334 1-247-855-11 CARBON 10K 5% 1/4W R335 1-247-855-11 CARBON 10K 5% 1/4W R336 1-247-847-11 CARBON 4.7K 5% 1/4W R337 1-249-409-11 CARBON 220 5% 1/4W F R338 1-249-413-11 CARBON 470 5% 1/4W F R339 1-247-903-00 CARBON 1M 5% 1/4W R340 1-247-903-00 CARBON 1M 5% 1/4W R341 1-247-855-11 CARBON 10K 5% 1/4W R342 1-247-855-11 CARBON 10K 5% 1/4W R345 1-249-417-11 CARBON 1K 5% 1/4W F R346 1-249-417-11 CARBON 1K 5% 1/4W F R347 1-247-871-11 CARBON 47K 5% 1/4W R348 1-249-871-11 CARBON 47K 5% 1/4W R349 1-247-849-11 CARBON 5.6K 5% 1/4W R350 1-247-849-11 CARBON 5.6K 5% 1/4W R351 1-247-871-11 CARBON 47K 5% 1/4W R352 1-247-871-11 CARBON 47K 5% 1/4W R356 1-249-417-11 CARBON 1K 5% 1/4W F R357 1-249-417-11 CARBON 1K 5% 1/4W F R358 1-247-855-11 CARBON 10K 5% 1/4W R359 1-247-855-11 CARBON 10K 5% 1/4W R360 1-249-409-11 CARBON 220 5% 1/4W F R361 1-247-825-11 CARBON 560 5% 1/4W R362 1-247-855-11 CARBON 10K 5% 1/4W R363 1-247-855-11 CARBON 10K 5% 1/4W R364 1-249-421-11 CARBON 6.8K 5% 1/4W R365 1-249-421-11 CARBON 6.8K 5% 1/4W R366 1-247-847-11 CARBON 4.7K 5% 1/4W R370 1-247-843-11 CARBON 3.3K 5% 1/4W R371 1-247-843-11 CARBON 3.3K 5% 1/4W R372 1-247-867-11 CARBON 33K 5% 1/4W R373 1-247-867-11 CARBON 33K 5% 1/4W R384 1-247-879-11 CARBON 100K 5% 1/4W R385 1-247-879-11 CARBON 100K 5% 1/4W R386 1-247-879-11 CARBON 100K 5% 1/4W R387 1-247-879-11 CARBON 100K 5% 1/4W R389 1-247-879-11 CARBON 100K 5% 1/4W R390 1-247-879-11 CARBON 100K 5% 1/4W R401 1-247-839-11 CARBON 2.2K 5% 1/4W R402 1-247-827-11 CARBON 680 5% 1/4W R403 1-249-417-11 CARBON 1K 5% 1/4W F R404 1-249-411-11 CARBON 330 5% 1/4W R405 1-247-825-11 CARBON 560 5% 1/4W R406 1-259-676-11 CARBON 1K 2% 1W MAIN www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks — 68 — R408 1-247-855-11 CARBON 10K 5% 1/4W R409 1-249-417-11 CARBON 1K 5% 1/4W F R410 1-247-847-11 CARBON 4.7K 5% 1/4W R411 1-247-807-11 CARBON 100 5% 1/4W R412 1-247-807-11 CARBON 100 5% 1/4W R413 1-247-855-11 CARBON 10K 5% 1/4W R414 1-247-855-11 CARBON 10K 5% 1/4W R500 1-247-807-11 CARBON 100 5% 1/4W R501 1-249-438-11 CARBON 56K 5% 1/4W R502 1-249-438-11 CARBON 56K 5% 1/4W R503 1-247-841-11 CARBON 2.7K 5% 1/4W R504 1-247-841-11 CARBON 2.7K 5% 1/4W R505 1-249-438-11 CARBON 56K 5% 1/4W R506 1-249-438-11 CARBON 56K 5% 1/4W R507 1-260-072-11 CARBON 4.7 5% 1/2W R508 1-260-072-11 CARBON 4.7 5% 1/2W R509 1-247-807-11 CARBON 100 5% 1/4W R516 1-260-076-11 CARBON 10 5% 1/2W R517 1-260-076-11 CARBON 10 5% 1/2W R521 1-249-389-11 CARBON 4.7 5% 1/4W F R522 1-249-389-11 CARBON 4.7 5% 1/4W F R525 1-260-083-11 CARBON 47 5% 1/2W R526 1-260-083-11 CARBON 47 5% 1/2W R527 1-249-393-11 CARBON 10 5% 1/4W F R551 1-208-601-11 REGISTER 0.1 10% 2W F R552 1-208-601-11 REGISTER 0.1 10% 2W F R553 1-247-879-11 CARBON 100K 5% 1/4W R554 1-247-879-11 CARBON 100K 5% 1/4W R555 1-247-839-11 CARBON 2.2K 5% 1/4W R556 1-247-839-11 CARBON 2.2K 5% 1/4W R557 1-249-431-11 CARBON 15K 5% 1/4W R558 1-249-431-11 CARBON 15K 5% 1/4W R559 1-247-839-11 CARBON 2.2K 5% 1/4W R560 1-249-430-11 CARBON 12K 5% 1/4W R561 1-249-430-11 CARBON 12K 5% 1/4W R562 1-247-871-11 CARBON 47K 5% 1/4W R563 1-247-855-11 CARBON 10K 5% 1/4W R564 1-247-879-11 CARBON 100K 5% 1/4W R565 1-247-847-11 CARBON 4.7K 5% 1/4W R566 1-249-417-11 CARBON 1K 5% 1/4W F R567 1-249-438-11 CARBON 56K 5% 1/4W R583 1-249-439-11 CARBON 68K 5% 1/4W R584 1-247-847-11 CARBON 4.7K 5% 1/4W R585 1-247-839-11 CARBON 2.2K 5% 1/4W R586 1-249-431-11 CARBON 15K 5% 1/4W R587 1-249-432-11 CARBON 18K 5% 1/4W R588 1-249-438-11 CARBON 56K 5% 1/4W R589 1-249-434-11 CARBON 27K 5% 1/4W R590 1-249-431-11 CARBON 15K 5% 1/4W R591 1-247-847-11 CARBON 4.7K 5% 1/4W < RELAY > RL501 1-515-921-11 RELAY (12V) < METAL RES > SFR101 1-228-995-00 RES, ADJ, METAL 22K SFR201 1-228-993-00 RES, ADJ, METAL 4.7K < TRIMMER > TC101 1-141-304-21 CAP, TRIMMER 10PF TC102 1-141-304-21 CAP, TRIMMER 10PF < TRANSFORMER > T101 1-429-553-11 TRANSFORMER, FM IFT T102 1-429-554-11 TRANSFORMER, AM IFT < VIBRATOR > X101 1-579-585-11 VIBRATOR, CRYSTAL 7.2MHz ************************************************************ * 1-670-801-11 MOTOR BOARD ************* < CAPACITOR > C01 1-126-963-11 ELECT 4.7uF 20% 50V C82 1-164-159-11 CERAMIC 0.1uF 50V < CONNECTOR > * CN06 1-568-824-11 SOCKET, CONNECTOR 5P ************************************************************ * 1-639-678-12 MOTOR (6P) (S) BOARD ******************* < CONNECTOR > CN1 1-564-722-11 PIN, CONNECTOR (SMALL TYPE) 6P < MOTOR > M101 X-2625-877-1 MOTOR ASSY (SPINDLE) M102 X-2625-769-1 MOTOR ASSY (SLED) < SWITCH > S1 1-572-085-11 SWITCH, LEAF (LIMIT) ************************************************************ * A-4414-553-A PANEL BOARD, COMPLETE ********************** * 4-210-348-01 HOLDER, LED < CAPACITOR > C601 1-164-159-11 CERAMIC 0.1uF 50V C602 1-126-933-11 ELECT 100uF 20% 16V C603 1-126-916-11 ELECT 1000uF 20% 6.3V C604 1-161-494-00 CERAMIC 0.022uF 25V C605 1-126-967-11 ELECT 47uF 20% 16V C606 1-164-159-11 CERAMIC 0.1uF 50V C607 1-126-961-11 ELECT 2.2uF 20% 50V C608 1-126-960-11 ELECT 1uF 20% 50V C609 1-164-159-11 CERAMIC 0.1uF 50V C610 1-126-967-11 ELECT 47uF 20% 16V C611 1-161-494-00 CERAMIC 0.022uF 25V C612 1-162-201-31 CERAMIC 12PF 5% 50V C613 1-162-201-31 CERAMIC 12PF 5% 50V C614 1-126-960-11 ELECT 1uF 20% 50V C615 1-162-282-31 CERAMIC 100PF 10% 50V MAIN MOTOR MOTOR (6P) (S) PANEL www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks — 69 — C616 1-130-491-00 MYLAR 0.047uF 5% 50V C617 1-130-491-00 MYLAR 0.047uF 5% 50V C619 1-130-491-00 MYLAR 0.047uF 5% 50V C620 1-126-933-11 ELECT 100uF 20% 16V C621 1-161-494-00 CERAMIC 0.022uF 25V C623 1-162-294-31 CERAMIC 0.001uF 10% 50V C624 1-162-294-31 CERAMIC 0.001uF 10% 50V C625 1-162-294-31 CERAMIC 0.001uF 10% 50V < CONNECTOR > * CN301 1-770-332-11 HOUSING, CONNECTOR (PC BOARD) 17P CN601 1-568-468-11 SOCKET, CONNECTOR 18P < DIODE > D601 8-719-911-19 DIODE 1SS119-25 D602 8-719-911-19 DIODE 1SS119-25 D603 8-719-911-19 DIODE 1SS119-25 D604 8-719-911-19 DIODE 1SS119-25 D605 8-719-911-19 DIODE 1SS119-25 D606 8-719-911-19 DIODE 1SS119-25 D607 8-719-911-19 DIODE 1SS119-25 D608 8-719-911-19 DIODE 1SS119-25 D609 8-719-911-19 DIODE 1SS119-25 D610 8-719-911-19 DIODE 1SS119-25 D611 8-719-911-19 DIODE 1SS119-25 < FLUORECENT INDICATOR > FLD601 1-517-761-11 INDICATOR TUBE, FLUORESCENT < IC > IC601 8-759-539-19 IC uPD780205GF-042-3BA IC602 8-759-275-23 IC BU2092 < COIL > L601 1-408-096-00 INDUCTOR 470uH L602 1-408-611-31 INDUCTOR 47uH < LED > LED601 8-719-046-80 DIODE SML19416W-TP4 LED602 8-719-044-69 DIODE SEL1910DTP3 < TRANSISTOR > Q601 8-729-194-57 TRANSISTOR 2SC945-P Q602 8-729-194-57 TRANSISTOR 2SC945-P Q603 8-729-194-57 TRANSISTOR 2SC945-P Q604 8-729-119-76 TRANSISTOR 2SA1175-HFE Q605 8-729-029-86 TRANSISTOR DTC124ESA Q606 8-729-029-86 TRANSISTOR DTC124ESA < RESISTOR > R601 1-247-871-11 CARBON 47K 5% 1/4W R602 1-249-417-11 CARBON 1K 5% 1/4W F R603 1-249-417-11 CARBON 1K 5% 1/4W F R604 1-247-871-11 CARBON 47K 5% 1/4W R605 1-247-871-11 CARBON 47K 5% 1/4W R606 1-249-417-11 CARBON 1K 5% 1/4W F R607 1-249-431-11 CARBON 15K 5% 1/4W R608 1-247-871-11 CARBON 47K 5% 1/4W R609 1-247-855-11 CARBON 10K 5% 1/4W R610 1-247-855-11 CARBON 10K 5% 1/4W R611 1-247-855-11 CARBON 10K 5% 1/4W R612 1-247-855-11 CARBON 10K 5% 1/4W R613 1-247-855-11 CARBON 10K 5% 1/4W R614 1-247-855-11 CARBON 10K 5% 1/4W R615 1-247-855-11 CARBON 10K 5% 1/4W R616 1-249-418-11 CARBON 1.2K 5% 1/4W F R617 1-249-420-11 CARBON 1.8K 5% 1/4W F R618 1-249-418-11 CARBON 1.2K 5% 1/4W F R619 1-249-420-11 CARBON 1.8K 5% 1/4W F R620 1-247-841-11 CARBON 2.7K 5% 1/4W R621 1-249-424-11 CARBON 3.9K 5% 1/4W F R622 1-249-427-11 CARBON 6.8K 5% 1/4W F R623 1-249-431-11 CARBON 15K 5% 1/4W R624 1-249-436-11 CARBON 39K 5% 1/4W R625 1-249-418-11 CARBON 1.2K 5% 1/4W F R626 1-249-420-11 CARBON 1.8K 5% 1/4W F R627 1-249-418-11 CARBON 1.2K 5% 1/4W F R628 1-249-420-11 CARBON 1.8K 5% 1/4W F R629 1-247-841-11 CARBON 2.7K 5% 1/4W R635 1-247-871-11 CARBON 47K 5% 1/4W R636 1-249-407-11 CARBON 150 5% 1/4W F R637 1-249-417-11 CARBON 1K 5% 1/4W F R638 1-249-417-11 CARBON 1K 5% 1/4W F R639 1-249-417-11 CARBON 1K 5% 1/4W F R640 1-247-839-11 CARBON 2.2K 5% 1/4W R641 1-247-839-11 CARBON 2.2K 5% 1/4W R642 1-247-839-11 CARBON 2.2K 5% 1/4W R643 1-247-855-11 CARBON 10K 5% 1/4W R644 1-247-855-11 CARBON 10K 5% 1/4W R645 1-247-855-11 CARBON 10K 5% 1/4W R646 1-247-855-11 CARBON 10K 5% 1/4W R647 1-247-855-11 CARBON 10K 5% 1/4W R648 1-247-855-11 CARBON 10K 5% 1/4W R649 1-249-407-11 CARBON 150 5% 1/4W F R650 1-249-409-11 CARBON 220 5% 1/4W F R651 1-247-855-11 CARBON 10K 5% 1/4W R652 1-247-855-11 CARBON 10K 5% 1/4W < SWITCH > S601 1-572-674-11 SWITCH, PUSH (TAPE) S602 1-572-674-11 SWITCH, PUSH (TUNER/BAND) S603 1-572-674-11 SWITCH, PUSH (CD PLAY/PAUSE) S604 1-572-674-11 SWITCH, PUSH (EDIT) S605 1-572-674-11 SWITCH, PUSH (TUNER MEMORY REPEAT) S606 1-572-674-11 SWITCH, PUSH (STEREO/MONO PLAY MODE) S607 1-572-674-11 SWITCH, PUSH (CD STOP) S608 1-572-674-11 SWITCH, PUSH (CD FF/TUNER UP) S609 1-572-674-11 SWITCH, PUSH (TUNER PRESET+) S610 1-572-674-11 SWITCH, PUSH (AMS + TU PRESET+) S611 1-572-674-11 SWITCH, PUSH (AMS – TU PRESET–) S612 1-572-674-11 SWITCH, PUSH (POWER) S613 1-572-674-11 SWITCH, PUSH (CLOCK TIMER SET) S614 1-572-674-11 SWITCH, PUSH (TIMER ON/OFF) S615 1-572-674-11 SWITCH, PUSH (ENTER/NEXT) PANEL www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks — 70 — S616 1-572-674-11 SWITCH, PUSH (FILE SELECT) S617 1-572-674-11 SWITCH, PUSH (DBFB) S618 1-572-674-11 SWITCH, PUSH (DISPLAY) < VIBRATOR > X601 1-760-096-11 VIBRATOR, CRYSTAL 4.1943MHz ************************************************************ * 1-666-444-11 R/P SWITCH BOARD **************** < CAPACITOR > C236 1-126-024-11 ELECT 220uF 20% 16V C244 1-161-494-00 CERAMIC 0.022uF 25V < DIODE > D206 8-719-904-02 DIODE 10E2 D207 8-719-904-02 DIODE 10E2 ************************************************************ * 1-670-388-11 SENSOR BOARD ************* < IC > RM601 8-749-013-84 IC SPS-447-1 ************************************************************ * 1-670-797-11 SW (A) BOARD ************ < SWITCH > S04 1-771-169-11 SWITCH (TURN TABLE OPERATION DET) ************************************************************ * 1-670-798-11 SW (B) BOARD ************ < SWITCH > S03 1-771-169-11 SWITCH (TURN TABLE POSITION DET) ************************************************************ * 1-670-799-11 SW (C) BOARD ************ < SWITCH > S02 1-571-300-31 SWITCH, ROTARY (OPEN/CLOSE DET) ************************************************************ * 1-670-800-11 SW (D) BOARD ************ < SWITCH > S01 1-571-300-31 SWITCH, ROTARY (OPTICAL PICK-UP DET) ************************************************************ * 1-670-389-11 VR BOARD ********* < CAPACITOR > C626 1-162-306-11 CERAMIC 0.01uF 20% 16V C627 1-162-306-11 CERAMIC 0.01uF 20% 16V < VARIABLE RESISTOR > VR601 1-475-807-11 ENCODER, ROTARY ************************************************************ MISCELLANEOUS *************** !6 1-559-583-11 CORD, POWER (US, CND) !6 1-551-506-99 CORD, POWER (MX, SAF) !6 1-696-966-11 CORD, POWER (AUS) 63 1-773-077-11 WIRE (FLAT TYPE) (18 CORE) 163 1-759-417-11 DECK, MECH 251 1-769-856-11 WIRE (FLAT TYPE) (5 CORE) !308 8-848-379-31 OPTICAL PICK-UP KSS-213B/S-N HE901 9-980-280-01 E HEAD (ERASE) HP901 9-980-287-01 HEAD (PLAY) HRP901 9-980-279-01 HEAD (REC/PLAY) M103 X-4948-765-1 MOTOR ASSY (TURN TABLE) M104 X-4948-766-1 MOTOR ASSY (A) (TRAY) M901 9-980-281-01 MOTOR (CAPSTAN/REEL) !PT302 1-431-939-11 TRANSFORMER, POWER (US, CND) !PT302 1-431-961-11 TRANSFORMER, POWER (MX, SAF) !PT302 1-431-962-11 TRANSFORMER, POWER (AUS) SW202 9-980-270-01 LEAF SWITCH (A DECK) SW203 9-980-270-01 LEAF SWITCH (B DECK) SW204 9-980-271-01 LEAF SWITCH (PLAY) ************************************************************ ACCESSORIES & PACKING MATERIALS ******************************* 1-475-826-11 REMOTE COMMANDER (RM-SG5) 1-501-594-11 ANTENNA, (FM) 1-501-374-11 ANTENNA , LOOP 3-862-423-11 MANUAL, INSTRUCTION (ENGLISH) 3-862-423-21 MANUAL, INSTRUCTION (FRENCH) 3-862-423-31 MANUAL, INSTRUCTION (SPANISH) 3-862-423-41 MANUAL, INSTRUCTION (FRENCHI/SPANISH/PORTUGUESE) 3-862-423-51 MANUAL, INSTRUCTION (GERMAN) 3-862-423-61 MANUAL, INSTRUCTION (DUTCH/ITALIAN) 3-862-423-71 MANUAL, INSTRUCTION R/P SWITCH SENSOR SW (A) SW (B) SW (C) SW (D) VR The components identified by mark ! or dotted line with mark ! are critical for safety. Replace only with part number specified. Les composants identifiés par une marque ! sont critiques pour la sécurité. Ne les remplacer que par une pièce portant le numéro spécifié. PANEL www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks — 71 — (SWEDISH/DANISH/FINNISH) 3-862-423-81 MANUAL, INSTRUCTION (POLISH/RUSSIAN) 4-982-031-01 COVER, BATTERY (for RM-SG5) ************************************************************ ************** HARDWARE LIST ************** #1 7-685-647-79 SCREW +BVTP 3 × 10 TYPE2 IT-3 #2 7-682-547-04 SCREW +BVTT 3 × 6 (S) #3 7-682-548-04 SCREW +B 3 × 8 #4 7-685-106-19 SCREW +P 2 × 10 TYPE2 SLIT #5 7-685-131-19 SCREW +P 2.6 × 4 TYPE2 SLIT #6 7-685-139-29 SCREW, TAPPING, (M2.6 × 20) #7 7-685-134-19 SCREW +PTPWH 2.6 × 8 (TYPE2) #8 7-685-138-19 SCREW +BTP 2.6 × 16 TYPE2 N-S #9 7-624-118-01 RING, RETAINING E-2.5 #10 7-685-903-31 SCREW +PTPWH 3 × 10 (TYPE2) #11 7-685-246-19 SCREW +KTP 3 × 8 TYPE2 NON-SLIT #12 7-685-547-14 SCREW +BTP 3 × 10 TYPE2 N-S #13 7-685-547-19 SCREW +BTP 3 × 10 TYPE2 N-S #14 7-685-549-14 SCREW +BTP 3 × 14 TYPE2 N-S #15 7-685-645-79 SCREW +BTP 3 × 6 TYPE2 N-S #16 7-685-660-79 SCREW +PTPWH 4 × 10 TYPE 2 #17 7-685-903-21 SCREW +PTPWH 3 × 8 (TYPE2) #18 7-621-255-15 SCREW +P 2 × 3 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com — 72 — HCD-GRX2/RX33 Sony Corporation Home A&V Products Company 9-922-792-11 98C167032-1 Printed in Singapore ©1998.3 Published by General Engineering Dept. (Shibaura) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com ––––––––––– –––––––––––––––––––––– 1-126-925-11 ELECT 470uF 20% 10V 1-162-201-31 CERAMIC 12PF 5% 50V ––––––––––– –––––––––––––––––––––– 1-162-294-31 CERAMIC 0.001uF 10% 50V ––––––––––– –––––––––––––––––––––– 1-136-154-00 FILM 0.012uF 5% 50V 1-162-306-11 CERAMIC 0.01uF 20% 16V 1-126-927-11 ELECT 2200uF 20% 10V 1-162-294-31 CERAMIC 0.001uF 10% 50V 1-102-942-00 CERAMIC 5PF 0.5PF 50V 1-102-942-00 CERAMIC 5PF 0.5PF 50V 1-126-934-11 ELECT 220uF 20% 10V 1-162-289-31 CERAMIC 390PF 10% 50V 1-162-289-31 CERAMIC 390PF 10% 50V 1-162-288-31 CERAMIC 330PF 10% 50V 1-162-288-31 CERAMIC 330PF 10% 50V 1-162-288-31 CERAMIC 330PF 10% 50V 1-162-288-31 CERAMIC 330PF 10% 50V ––––––––––– –––––––––––––––––––––– 1-162-294-31 CERAMIC 0.001uF 10% 50V 1-162-294-31 CERAMIC 0.001uF 10% 50V 1-162-294-31 CERAMIC 0.001uF 10% 50V 1-162-294-31 CERAMIC 0.001uF 10% 50V 1-164-159-11 CERAMIC 0.1uF 50V 8-719-991-33 DIODE ISS133T 8-719-921-41 DIODE MTZJ-5.1 8-719-991-33 DIODE ISS133T 8-759-234-75 IC TC74HC4094AP 8-759-579-80 IC BA5936S 1-249-393-11 CARBON 10 5% 1/4W 1-249-438-11 CARBON 56K 5% 1/4W 1-249-440-11 CARBON 82K 5% 1/4W 1-249-431-11 CARBON 15K 5% 1/4W 1-249-385-11 CARBON 2.2 5% 1/4W 1-274-871-11 CARBON 47K 5% 1/4W 1-249-411-11 CARBON 330 5% 1/4W 1-247-867-11 CARBON 33K 5% 1/4W 1-249-432-11 CARBON 18K 5% 1/4W 1-249-417-11 CARBON 1K 5% 1/4W 1-247-867-11 CARBON 33K 5% 1/4W 1-247-867-11 CARBON 33K 5% 1/4W 1-247-867-11 CARBON 33K 5% 1/4W 1-247-867-11 CARBON 33K 5% 1/4W 1-249-409-11 CARBON 220 5% 1/4W 1-249-432-11 CARBON 18K 5% 1/4W 1-247-855-11 CARBON 10K 5% 1/4W 1-249-432-11 CARBON 18K 5% 1/4W 1-247-855-11 CARBON 10K 5% 1/4W 1-247-867-11 CARBON 33K 5% 1/4W 1-247-863-11 CARBON 22K 5% 1/4W US Model Canadian Model HCD-RX33 E Model Australian Model HCD-GRX2 SERVICE MANUAL CORRECTION-2 Correct your service manual as shown below. • PARTS LIST Page CORRECT Ref. No. Part No. Description Remarks Part No. Description Remarks C02 1-126-963-11 ELECT 4.7uF 20% 50V C04B ––––––––––– –––––––––––––––––––––– C07A 1-162-199-31 CERAMIC 10PF 5% 50V C08 1-161-494-00 CERAMIC 0.022uF 25V C23A ––––––––––– –––––––––––––––––––––– C26 1-161-494-00 CERAMIC 0.022uF 25V C27 1-162-306-11 CERAMIC 0.01uF 20% 16V C28 1-164-159-11 CERAMIC 0.1uF 50V C29A ––––––––––– –––––––––––––––––––––– C30B ––––––––––– –––––––––––––––––––––– C38 1-102-958-00 CERAMIC 20PF 5% 50V C39 1-102-958-00 CERAMIC 20PF 5% 50V C46 1-126-933-11 ELECT 100uF 20% 10V C51 1-162-288-31 CERAMIC 330PF 10% 50V C52 1-162-288-31 CERAMIC 330PF 10% 50V C53 1-162-284-31 CERAMIC 150PF 10% 50V C54 1-162-284-31 CERAMIC 150PF 10% 50V C55 1-162-284-31 CERAMIC 150PF 10% 50V C56 1-162-284-31 CERAMIC 150PF 10% 50V C84 1-162-282-31 CERAMIC 100PF 10% 50V C85 1-162-292-31 CERAMIC 680PF 10% 50V C86 1-162-282-31 CERAMIC 100PF 10% 50V C87 1-162-282-31 CERAMIC 100PF 10% 50V C88 1-162-282-31 CERAMIC 100PF 10% 50V C90 1-161-494-00 CERAMIC 0.022uF 25V D01 8-719-911-19 DIODE ISS119-25 D04 8-719-921-41 DIODE ISS113T D04A 8-719-991-33 DIODE ISS176 IC02 8-759-388-27 IC TC9173P IC03 8-759-429-31 IC BA5941FP R03 1-249-397-11 CARBON 22 5% 1/4W R14 1-247-879-11 CARBON 100K 5% 1/4W R15 1-247-881-00 CARBON 120K 5% 1/4W R26 1-247-855-11 CARBON 10K 5% 1/4W R27 1-249-430-11 CARBON 12K 5% 1/4W R28 1-247-855-11 CARBON 10K 5% 1/4W R36 1-247-847-11 CARBON 4.7K 5% 1/4W R50 1-247-847-11 CARBON 4.7K 5% 1/4W R53 1-249-411-11 CARBON 330 5% 1/4W R58 1-249-442-11 CARBON 510 5% 1/4W R65 1-247-864-11 CARBON 24K 5% 1/4W R66 1-247-864-11 CARBON 24K 5% 1/4W R67 1-247-864-11 CARBON 24K 5% 1/4W R68 1-247-864-11 CARBON 24K 5% 1/4W R79 1-249-405-11 CARBON 100 5% 1/4W R89 1-247-839-11 CARBON 2.2K 5% 1/4W R90 1-247-839-11 CARBON 2.2K 5% 1/4W R91 1-247-839-11 CARBON 2.2K 5% 1/4W R92 1-247-839-11 CARBON 2.2K 5% 1/4W R93 1-249-420-11 CARBON 1.8K 5% 1/4W R94 1-249-420-11 CARBON 1.8K 5% 1/4W INCORRECT 61 62 — 2 — Sony Corporation Home A&V Products Company 9-922-792-92 98L1632-1 Printed in Japan ©1998.12 Published by Quality Assurance Dept. (Shibaura) Subject : Correction of electrical parts. (ECN-TA803970) (ECN-TA803983) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com : Indicates corrected portion — 3 — — 4 — (ADDED) (DELETED) (ADDED) (DELETED) (ADDED) (DELETED) (DELETED) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com
