HCD-GP7 AEP Model UK Model SERVICE MANUAL MICRO HI-FI COMPONENT SYSTEM Sony Corporation Home Audio Company Published by Sony Engineering Corporation 9-877-470-02 2003K16-1 © 2003.11 HCD-GP7 is the Amplifier, CD player, Tape Deck and Tuner section in CMT-GP7. SPECIFICATIONS Ver 1.1 2003. 11 Main unit Amplifier section DIN power output (rated): 40 + 40 watts (6 ohms at 1 kHz, DIN) Continuous RMS power output (reference): 50 + 50 watts (6 ohms at 1 kHz, 10% THD) Inputs MD (VIDEO) (phono jacks): Sensitivity 450/250 mV, impedance 47 kilohms Outputs PHONES: Accepts headphones with an impedance of 8 ohms or more SPEAKER: Accepts impedance of 6 to 16 ohms. CD player section Laser Semiconductor laser (λ=780 nm) Emission duration: continuous Frequency response 20 Hz – 20 kHz Wavelength 780 – 790 nm Tape deck section Recording system 4-track 2-channel, stereo Frequency response 50 – 13,000 Hz (±3 dB), using Sony TYPE I cassettes Tuner section FM stereo, FM/AM superheterodyne tuner FM tuner section Tuning range 87.5 – 108.0 MHz (50 kHz step) Antenna FM lead antenna Antenna terminals 75 ohms unbalanced Intermediate frequency 10.7 MHz AM tuner section Tuning range 531 – 1,602 kHz (with the tuning interval set at 9 kHz) Antenna AM loop antenna, external antenna terminal Intermediate frequency 450 kHz General Power requirements 230 V AC, 50/60 Hz Power consumption 100 watts 0.3 watts (in Power Saving Mode) Dimensions (w/h/d) Approx. 190 × 250 × 340 mm incl. projecting parts and controls Mass Approx. 6.2 kg Supplied accessories: Remote (1) R6 (size AA) batteries (2) AM loop antenna (1) FM lead antenna (1) Design and specifications are subject to change without notice. Model Name Using Similar Mechanism NEW CD CD Mechanism Type CDM55A-K6BD47S Section Base Unit Name BU-K6BD71C Optical Pick-up Name KSM-213D TAPE Model Name Using Similar Mechanism HCD-EP515 Section Tape Transport Mechanism Type CMAL1Z240A www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 2 HCD-GP7 1. SERVICING NOTES ······················································· 3 2. GENERAL ·········································································· 5 3. DISASSEMBLY ································································ 7 3-1. Top Case, MAIN Board, Back Panel Assy ···················· 8 3-2. Front Panel Assy, CD Mechanism Deck ······················· 9 3-3. PANEL Board, HP Board, VOL Board ······················· 10 3-4. TC Board, single cassette mechanism (CMAL1Z240A) ························································· 10 3-5. CD Mechanism (CDM55A-K6BD47S) ······················ 11 3-6. THR Board, DC FAN ·················································· 11 3-7. SPEAKER Board, POWER-AMP Board ···················· 12 3-8. SUB-POWER Board, POWER Board························· 12 3-9. LOADING Board ························································ 13 3-10.CD Board····································································· 13 3-11.Tray (CDM55D) ·························································· 14 3-12.Optical Pick-Up (KSM-213D) ···································· 14 4. TEST MODE ···································································· 16 5. MECHANICAL ADJUSTMENTS ····························· 17 6. ELECTRICAL ADJUSTMENTS ······························· 17 7. DIAGRAMS ······································································ 22 Contents CIRCUIT BOARD LOCATION ·········································· 23 7-1. Block Diagram — CD Section — ······························· 24 — TUNER/TAPE Section — ······································ 25 — AMP Section — ····················································· 26 — DISPLAY/POWER SUPPLY Section — ··············· 27 7-2. Printed Wiring Board — CD Section — ····················· 28 7-3. Schematic Diagram — CD Section — ························ 29 7-4. Printed Wiring Board — TC Section —······················ 30 7-5. Schematic Diagram — TC Section — ························ 31 7-6. Printed Wiring Board — MAIN Section — ················ 32 7-7. Schematic Diagram — MAIN Section —··················· 33 7-8. Printed Wiring Board — PANEL Section — ·············· 34 7-9. Schematic Diagram — PANEL Section — ················· 35 7-10.Printed Wiring Board — POWER AMP Section — ··· 36 7-11.Schematic Diagram — POWER AMP Section — ······ 37 7-12.Printed Wiring Board — POWER Section — ············· 38 7-13.Schematic Diagram — POWER Section — ··············· 38 8. EXPLODED VIEWS 8-1. Over All Section ·························································· 47 8-2. Front Panel Section ····················································· 48 8-3. Chassis Section ···························································· 49 8-4. CD Mechanism Section ··············································· 50 8-5. KSM-213D ·································································· 51 9. ELECTRICAL PARTS LIST ······································· 52 TABLE OF CONTENTS Ver 1.1 2003.11 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 3 HCD-GP7 SECTION 1 SERVICING NOTES Notes on chip component replacement • Never reuse a disconnected chip component. • Notice that the minus side of a tantalum capacitor may be dam- aged by heat. Flexible Circuit Board Repairing • Keep the temperature of the soldering iron around 270 ˚C during repairing. • Do not touch the soldering iron on the same conductor of the circuit board (within 3 times). • Be careful not to apply force on the conductor when soldering or unsoldering. This appliance is classified as a CLASS 1 LASER product. This label is located on the rear exterior. Laser component in this product is capable of emitting radiation exceeding the limit for Class 1. The laser diode in the optical pick-up block may suffer electrostatic break-down because of the potential difference generated by the charged electrostatic load, etc. on clothing and the human body. During repair, pay attention to electrostatic break-down and also use the procedure in the printed matter which is included in the repair parts. The flexible board is easily damaged and should be handled with care. CAUTION Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure. NOTES ON HANDLING THE OPTICAL PICK-UP BLOCK OR BASE UNIT NOTES ON LASER DIODE EMISSION CHECK The laser beam on this model is concentrated so as to be focused on the disc reflective surface by the objective lens in the optical pick- up block. Therefore, when checking the laser diode emission, observe from more than 30 cm away from the objective lens. LASER DIODE AND FOCUS SEARCH OPERATION CHECK Carry out the “S curve check” in “CD section adjustment” and check that the S curve waveforms is output three times. UNLEADED SOLDER Boards requiring use of unleaded solder are printed with the lead- free mark (LF) indicating the solder contains no lead. (Caution: Some printed circuit boards may not come printed with the lead free mark due to their particular size) : LEAD FREE MARK Unleaded solder has the following characteristics. • Unleaded solder melts at a temperature about 40 ˚C higher than ordinary solder. Ordinary soldering irons can be used but the iron tip has to be applied to the solder joint for a slightly longer time. Soldering irons using a temperature regulator should be set to about 350 ˚C . Caution: The printed pattern (copper foil) may peel away if the heated tip is applied for too long, so be careful! • Strong viscosity Unleaded solder is more viscous (sticky, less prone to flow) than ordinary solder so use caution not to let solder bridges occur such as on IC pins, etc. • Usable with ordinary solder It is best to use only unleaded solder but unleaded solder may also be added to ordinary solder. SAFETY-RELATED COMPONENT WARNING!! COMPONENTS IDENTIFIED BY MARK 0 OR DOTTED LINE WITH MARK 0 ON THE SCHEMATIC DIAGRAMS AND IN THE PARTS LIST ARE CRITICAL TO SAFE OPERATION. REPLACE THESE COMPONENTS WITH SONY PARTS WHOSE PART NUMBERS APPEAR AS SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUBLISHED BY SONY. CAUTION : Not to Contact with the heat Sink. MAIN board heat sink Lead pin Secure the respective cables firmly with the lead pins so as not to contact them with the heat sink. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 4 HCD-GP7 Service Position of the Tape Cassette Mechanism Deck Service Position of the CD Mechanism Deck MAIN board Tape Cassette Mechanism Deck (CMAL1Z240A) MAIN board CD Mechanism Deck (CDM55A-K6BD47S) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 5 HCD-GP7 SECTION 2 GENERAL This section is extracted from instruction manual. Main unit Cassette compartment qg CD SYNC qd (16) DIRECTION 9 (15, 16, 17, 19) Disc tray 4 Display window 3 DSG qa (17) MD (VIDEO) qj (22) PHONES jack qh PLAY MODE/TUNING MODE 9 (8, 10, 12, 13, 26) Remote sensor 2 REPEAT/FM MODE 8 (10, 14) TUNER/BAND qj (12, 13) TUNING +/– 6 (12, 13) VOLUME* 7 (18) ?/1 (power) 1 (7, 12, 18, 19, 23, 26) .m/M> (go back/go forward, rewind/fast forward) 6 (7, 9, 10, 15, 17, 18, 19) x (stop) qs (9, 12, 15, 16, 17, 26) REC PAUSE/START z qf (16, 17) CD NX (play/pause) qk (8, 10) TAPE nN (play) qk (15, 16, 17, 19) Z (CD open/close) 5 (8, 9) Z PUSH (tape open/close) 0 (15) * To adjust the volume, first press this control, and then turn it. List of button locations and reference pages How to use this page Use this page to find the location of buttons and other parts of the system that are mentioned in the text. Illustration number r DISPLAY 5 (14, 20, 21) R R Name of button/part Reference page ALPHABETICAL ORDER A – M P – Z BUTTON DESCRIPTIONS 1 2 3 4 5 6 7 8 qk qj qh 9 0 qa qs qd qf qg www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 6 HCD-GP7 Remote control ALBUM +/– 8 (9, 10) BASS/TREBLE qa (17) CLEAR 3 (11) CLOCK/TIMER SELECT qh (19, 20) CLOCK/TIMER SET qj (7, 18, 19) DISPLAY 5 (14, 20, 21) DSG 0 (17) ENTER qg (7, 9, 10, 12, 18, 19) FUNCTION 9 (8, 10, 12, 15, 22) Numeric buttons 2 (9, 11, 13) PRESET +/– 6 (12, 13) SLEEP qf (18) TUNER MEMORY qd (12) TUNING +/– 7 (12, 13) VOL +/– 4 (18) ?/1 (power) 1 (7, 12, 18, 19, 23, 26) m/M (rewind/fast forward) 7 (9, 15) ./> (go back/go forward) 6 (7, 9, 10, 17, 18, 19) x (stop) qs (9, 12, 15, 16, 17) X (pause) qs (9, 15) N (play) qs (8, 10, 15, 16, 17, 19) ALPHABETICAL ORDER A – F N – Z BUTTON DESCRIPTIONS 1 3 qg qd qf qs 0 qa 9 2 4 5 6 qj qh 7 8 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 7 HCD-GP7 SECTION 3 DISASSEMBLY • This set can be disassembled in the order shown below. POWER BOARD, SUB-POWER BOARD LOADING BOARD CD BOARD TRAY (CDM55D) OPTICAL PICK-UP (KSM-213D), HOLDER (C213) PANEL BOARD, HP BOARD, VOL BOARD TC BOARD, SINGLE CASSETTE MECHANISM THR BOARD, DC FAN SPEAKER BOARD, POWER-AMP BOARD FRONT PANEL ASSY, CD MECHANISM DECK (CDM55A-K6BD47S) SET TOP CASE, BACK PANEL, MAIN BOARD Ver 1.1 2003.11 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 8 HCD-GP7 Note: Follow the disassembly procedure in the numerical order given. 3-1. Top Case, MAIN Board, Back Panel Assy a a b b 4 top case qh MAIN board 1 three screws (+BVTP 3 ×10) 2 three screws (+BVTP 3 ×10) 3 five screws (+BVTT 3 ×8) 8wire (flat type) 11p tuner (FM/AM) qj connector (CN962) qa connector (CN401) qs connector (CN306) qf connector (CN304) qd connector (CN302) qk connector (CN972) qg connector (CN303) 5 three screws (+BVTP 3 ×10) 7 screw (+BVTP 3 ×10) 6 five screws (+BVTT 3 ×8) ql back panel 9 screw (+BVTP 3 ×10) 0 screw (+BVTP 3 ×10) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 9 HCD-GP7 3-2. Front Panel Assy, CD Mechanism Deck 6 two screws (+BVTT 3 ×8) 5 8 front panel assy 7 connector 4p (CNJ331) 2 CD lid 3 four screws (+BVTP 3 ×12) 1 four claws 4 CD mechanism deck www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 10 HCD-GP7 3-3. PANEL Board, HP Board, VOL Board 3-4. TC Board, single cassette mechanism(CMAL1Z240A) 2 HP board 8 volume knob 7 PANEL board 0 VOL board qa VOL bracket 1 york bracket 3 ten screws (+BVTP 3 ×10) 9 two screws (+BVTP 3 × 8) 4 four screws (+BVTP 3 × 10) 5 wire (flat type) 17p (CN801) 6 connector 3p (CN811) 9 single cassette mechanism (CMAL1Z240A) 5 TC board 8 two screws (+BVTP 3 ×10) 4 three screws (+BTP 2.6 ×6) 6 screw (+BTP 2.6 ×6) 7 two screws (+BVTP 3 ×10) 2 wire (flat type) 19p (CN603) 3 wire (flat type) 8p (CN602) 1 connector 6p www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 11 HCD-GP7 3-5. CD Mechanism (CDM55A-K6BD47S) 3-6. THR Board, DC FAN 4 3 screw (+BVTP 3 ×10) 1 CD plate 5 CD holder 2 wire (flat type) 31p (CN101) 6 CD mechanism deck (CDM55A-K6BD47S) CN101 3 three screws (+BVTT 3 ×10) 0 four screws (+BVTT 3 ×8) 1 three screws (+BVTP 3 ×10) 2 tuner(FM/AM) 6 screw (+BVTT 3 ×8) qa four screws (+BVTP 3 ×10) 8 screw 9 screw 4 heat sink cover qd fan bracket qs DC fan 7 THR board 5 connector 2p (CN992) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 12 HCD-GP7 3-7. SPEAKER Board, POWER-AMP Board 3-8. SUB-POWER Board, POWER Board 3 SPEAKER board 8 POWER-AMP board 0 heat sink qa back panel 6 amp(pwb) bracket 2 two screws (+BVTP 3 ×10) 1 connector 6p (CN982) 5 screw (+BVTT 3 ×8) 4 screw (+BVTP 3 ×10) 7 two screws (+BVTP 3 ×16) 9 two screws (+BVTT 3 ×12) 3 two screws (+BVTT 3 × 8) 2 two screws (+BV SUMITITE B3) 7 four screws (+BV SUMITITE 4 × 8) 4 power bracket 1 connector 9p (CN951) T901 6 power cord 5 SUB-POWER board 8 POWER board www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 13 HCD-GP7 3-9. LOADING Board 3-10. CD Board 5 LOADING board 2 two screws (+BTP 2.6 × 6) 4 motor (LD) assy (M901) 1 Remove the belt. 3 Remove soldering from the two points. 2 Remove soldering from the four points. 3 wire (flat type) 16p 5 CD board 4 wire (flat type) 21p (CN101) 1 screw(+P 2.6 × 5) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 14 HCD-GP7 3-11. Tray (CDM55D) 3-12. Optical Pick-Up (KSM-213D), Holder (C213) 2 tray 1 While pressing the two protrusions A and B to unlock the two claws as shown, pull the tray in the direction of the arrow C. (Be careful of the claws.) claw claw C A B 1 two floating screws (+PTPWH M2.6) qf floating screws (+PTPWH M2.6) qg holder (C213) 5 screw (+PTTP M2.6) 6 stopper (BU) 2 two compression spring (T213) 7 compression spring (T213) 3 insulator 8 insulator 9 screw (+PTTP M2.6) q; stopper (BU) qa compression spring (T213) qs insulator qd optical pick-up (KSM-213DCP/C2NP) 4 insulator www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 15 HCD-GP7 MEMO www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 16 HCD-GP7 SECTION 4 TEST MODE [Cold Reset] * The cold reset clears all data including preset data stored in the RAM to initial conditions. Execute this mode when returning the set to the customer. Procedure: 1. Press the ?/1 button to turn the set on. 2. Press three buttons x , PLAY MODE and ?/1 simultaneously. 3. All of settings are reset. Then the power is turned off and the clock is displayed. [Panel Test Mode] * This mode is used to check the software version, the fluorescent indicator tube, LED and keyboard. Procedure: 1. Press the ?/1 button to turn the set on. 2. Press three buttons x , PLAY MODE and TUNER/BAND simultaneously. 3. Segments of the fluorescent indicator tube and LED are all turned on. 4. Version Check : When entering this mode, press the REPEAT button. The model name (“GP7”) and destination are displayed. 5. Each time the REPEAT button is pressed, the display changes “MC, GC, CD, CDD, CDMA, CDMB, BDA, BDB, ST, TA, TM, TC and MD (returns to MC) in this order. 6. When the DSG button is pressed while the version numbers are displayed, year, month and day of the software creation appear. When the DSG button is pressed again, the display returns to the software version display. When the REPEAT button is pressed while year, month and day of the software creation are being displayed, those are displayed in the same order of version display. 7. Key Check : Press the PLAY MODE button and the key check mode is activated. In the key check mode, the fluorescent indicator tube displays “K 0 V 0”. Each time a button is pressed, “K 0” value increases. However, once a button is pressed, it is no longer taken into account. Key check ends at “K 14 V 0”. 8. “V 0” value increases like 1, 2, 3 ... if rotating the VOLUME knob clockwise, or it decreases like 0, 9, 8, ... if rotating counter-clockwise. 9. To exit from this mode, press three buttons in the same manner as step 2, or disconnect the power cord. [Common Test Mode] Procedure: 1. Press the ?/1 button to turn the set on. 2. Press three buttons x , PLAY MODE and TAPE nN simultaneously. 3. The common test mode is activated and “SLEEP” and “DAILY” segments flash. 3-1. Amp Test Mode 1. In the common test mode, every time you press the BASS/ TREBLE button on the remote commander, the following items changes in the order as shown below. 2. When the VOLUME knob is turned clockwise or the VOL + button on the remote commander is pressed, volume goes MAX. 3. When the VOLUME knob is turned counter-clockwise or the VOL - button on the remote commander is pressed, volume goes MIN. 4. To exit from this mode, press the ?/1 button and disconnect the power cord. 3-2. Tape Test 1. Check the set is in the common test mode. 2. Insert a recordable cassette tape. 3. Input audio signal into the MD IN (J301). 4. Press z REC/PAUSE/START button. 5. Select the recording direction with the TAPE nN button. 6. Press z REC/PAUSE/START button to start recording. 7. When the . m - or + M > button against the tape recording direction is pressed, the tape is rewound to the recording started point and the set starts playback. 8. To exit from this mode, press the ?/1 button and disconnect the power cord. [CD Ship Mode] * This mode moves the optical pick-up to the position durable to vibration. Use this mode when returning the set to the customer after repair. Procedure: 1. Press the ?/1 button to turn the set on. 2. Set the function to CD. 3. Press three buttons x , PLAY MODE and CD u simultaneously. 4. A message “LOCK” is displayed on the fluorescent indicator tube, and the CD ship mode is set. Disconnect the power cord. [Ship Mode] * This mode is the combination of CD ship mode and cold reset. Procedure: 1. Press the ?/1 button to turn the set on. 2. Set the function to CD. 3. Press three buttons x , REPEAT and ?/1 simultaneously. 4. A message “LOCK” is displayed on the fluorescent indicator tube, and the CD ship mode is set. Disconnect the power cord. [CD Service Mode] * This mode can run the CD sled motor freely. Use this mode, for instance, when cleaning the pickup. Procedure: 1. Press the ?/1 button to turn the set on. 2. Set the function to CD. 3. Press three buttons x , REPEAT and CD u simultaneously. 4. The CD service mode is selected. 5. With the CD in stop status, press the + M > button to move the pickup to outside track (“SLED OUT” is displayed.), or press the . m - button to inside track (“SLED IN” is displayed.). 6. To exit from this mode, disconnect the power cord. [Disc Tray Lock] The disc tray lock function for the antitheft of an demonstration disc in the store is equipped. Setting Procedure: 1. Press the ?/1 button to turn the set on. 2. Press two buttons of x and Z simultaneously for five seconds. 3. The message “LOCKED” is displayed and the tray is locked. Releasing Procedure: 1. Press two buttons of x and Z simultaneously for five seconds again. 2. The message “UNLOCKED” is displayed and the tray is unlocked. Note : When “LOCKED” is displayed, the tray lock is not released by turning power on/off with the ?/1 button. [MD/VIDEO Function Selection Mode] * This mode is used to select the function of MD or VIDEO. Procedure: 1. Press the ?/1 button to turn the set off. 2. Press the MD and ?/1 buttons simultaneously. 3. The function will change from MD to VIDEO, and “VIDEO” is displayed. 4. To change change back to MD, repeat the same procedure. “TONE MAX” (BASS/TRE MAX) “TONE MIN” (BASS/TRE MIN) “TONE FLAT” (BASS/TRE FLAT) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 17 HCD-GP7 SECTION 5 MECHANICAL ADJUSTMENTS SECTION 6 ELECTRICAL ADJUSTMENTS 0 dB=0.775 V DECK SECTION 1. Demagnetize the record/playback head with a head demagnetizer. 2. Do not use a magnetized screwdriver for the adjustments. 3. After the adjustments, apply suitable locking compound to the parts adjust. 4. The adjustments should be performed with the rated power supply voltage unless otherwise noted. 5. The adjustments should be performed in the order given in this service manual. (As a general rule, playback circuit adjustment should be completed before performing recording circuit adjustment.) 6. The adjustments should be performed for both L-CH and R- CH. 7. Switches and controls should be set as follows unless otherwise specified. • Test Tape [Record/Playback Hrad Azimuth Adjustment] Procedure: 1. Mode: Playback Tape Signal Used for P-4-A100 10 kHz, –10 dB Azimuth Adjustment 3.04 – 6.96 mN • m (31 to 71 g • cm) (0.43 – 0.98 oz • inch) 0.20 – 0.58 mN • m (2 to 6 g • cm) (0.02 – 0.08 oz • inch) 3.04 – 6.96 mN • m (31 to 71 g • cm) (0.43 – 0.98 oz • inch) 0.20 – 0.58 mN • m (2 to 6 g • cm) (0.02 – 0.08 oz • inch) 6.97 – 14.02 mN • m (71 to 143 g • cm) (0.98 – 1.99 oz • inch) 9.8 mN • m or more (100 g • cm or more) (1.4 oz • inch or more) 9.8 mN • m or more (100 g • cm or more) (1.4 oz • inch or more) CQ-102C CQ-102C CQ-102RC CQ-102RC CQ-201B CQ-403A CQ-403R Precaution 1. Clean the following parts with a denatured alcohol-moistened swab: record/playback heads pinch rollers erase head rubber belts capstan idlers 2. Demagnetize the record/playback head with a head demag- netizer. 3. Do not use a magnetized screwdriver for the adjustments. 4. After the adjustments, apply suitable locking compound to the parts adjusted. 5. The adjustments should be performed with the rated power supply voltage unless otherwise noted. Torque Measurement Mode FWD FWD back tension REV REV back tension FF/REW FWD tension REV tension Torque meter Meter reading set MAIN board CN302 Pin 4 (L-CH) Pin 6 (R-CH) MAIN board CN302 Pin 2 (GND) + – level meter test tape P-4-A100 (10 kHz, –10 dB) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 18 HCD-GP7 2. Turn the adjustment screw and check output peaks. If the peaks do not match for L-CH and R-CH, turn the adjustment screw so that outputs match within 1dB of peak. 3. Mode: Playback 4. Repeat step 1 to 3 in playback (REV) mode. 5. After the adjustments, apply suitable locking compound to the pats adjusted. Adjustment Location: Record/Playback/Erase Head. [Rec Bias Adjustment] Procedure: In the common test mode, the “Tape test mode” is convenient for this adjustment. In the “Tape test mode”, when the REC starts the input signal FUNCTION is switched to MD automatically. When the REC stops, the tape returns near to the recording start position. 1. Press MD (VIDEO) button to select MD. (This step is not necessary if the above test mode has already been set) 2. Insert a tape into deck B. 3. After press z REC PAUSE/START button, press z REC PAUSE/START button, then recording start. 4. Mode: Record 5. Mode: Playback 6. Confirm the playback signal recorded in step 3 becomes adjustable level as follows. If these levels are not adjustable level, adjust the RV653 (L-CH) and RV603 (R-CH) on the TC board to repeat steps 4 and 5. Adjustable level: Playback output of 315 Hz to playback output of 10 kHz: ±1.0 dB Adjustment Location: TC board & MAIN board Screw position L-CH peak within 1dB Output level L-CH peak R-CH peak within 1dB Screw position R-CH peak MAIN board CN302 set test tape P-4-A100 (10 kHz, –10 dB) pin 6 oscilloscope L-CH R-CH V H waveform of oscilloscope in phase 45°� 90°� 135°�180°� good wrong pin 2 pin 4 L R + – set recorded portion MAIN board CN302 Pin 2 (GND) MAIN board CN302 Pin 4 (L-CH) Pin 6 (R-CH) level meter forward reverse attenuator set MAIN board MD (VIDEO)(J301) 1) 315 Hz 2) 10 kHz 50 mV (–23.8 dB) � � � 600 Ω blank tape CN-123 AF OSC www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 19 HCD-GP7 Adjustment Location 18 19 1 2 CN302 IC401 IC602 RV653 (L-CH) RV603 (R-CH) Rec Bias Adjustment [MAIN board] (Conductor Side) [TC board] (Component Side) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 20 HCD-GP7 RFAC Level Check Connection: Procedure: 1. Connect an oscilloscope to test point TP5 (RFAC) and TP 7(DVC) on the CD board. 2. Turn the power on. 3. Put the disc (YEDS-18) in to playback the number five track. 4. Confirm that oscilloscope waveform is clear and check RFAC signal level is correct or not. Note: A clear RFAC signal waveform means that the shape “◊” can be clearly distinguished at the center of the waveform. RFAC signal waveform Checking Location: CD board (SIDE B) (See page 21) + – CD board TP5 (RFAC) TP7 (DVC) oscilloscope VOLT/DIV: 200 mV TIME/DIV: 500 ns level: 0.9 ± 0.4 Vp-p CD SECTION Note: 1. CD Block is basically designed to operate without adjustment. There- fore, check each item in order given. 2. Use YEDS-18 disc (3-702-101-01) unless otherwise indicated. 3. Use an oscilloscope with more than 10MΩ impedance. 4. Clean the object lens by an applicator with neutral detergent when the signal level is low than specified value with the following checks. S-curve Check Connection: Procedure: 1. Connect an oscilloscope to test point TP4 (FE) and TP 7(DVC) on the CD board. 2. Turn the power on. 3. Put the disc (YEDS-18) in and turned power switch on again and actuate the focus search. (actuate the focus search when disc table is moving in and out) 4. Check the oscilloscope waveform (S-curve) is symmetrical between A and B. And confirm peak to peak level within 2.4 ± 1 Vp-p. S-curve waveform Note: • Try to measure several times to make sure than the ratio of A : B or B : A is more than 10 : 7. • Take sweep time as long as possible and light up the brightness to obtain best waveform. Checking Location: CD board (SIDE B) (See page 21) + – CD board TP4 (FE) TP7 (DVC) oscilloscope A B symmetry within 2.4 ± 1 Vp-p www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 21 HCD-GP7 E-F Balance Check Connection: Procedure: 1. Connect an oscilloscpe to test point TP2 (TE) and TP7 (DVC) on the CD board. 2. Turn the power on. 3. Select the function “CD”. 4. Press three buttons of x , [REPEAT] and CD u simultaneously to set the CD service mode. 5. Put the disc (YEDS-18) in to playback the number five track. 6. Press the [REPEAT] button. The message “TRAVERSE” is displayed. (The tracking servo and the sledding servo are turned OFF) 7. Check the level B of the oscilliscope's waveform and the A (DC voltage) of the center of the Traverse waveform. Confirm the following : A/B x 100 = less than ± 22% Traverse Waveform 8. Press the [REPEAT] button. The message “TRAVERSE” is displayed. (The tracking servo and sledding servo are turned ON) Confirm the C (DC voltage) is almost equal to the A (DC voltage) is step 5. 9. To exit from this mode, disconnect the power cord. Traverse Waveform Checking Location: CD board (SIDE B) (See page 24.) + – CD board TP2 (TE) TP7 (DVC) oscilloscope 0V B level: 1.0 ± 0.5 Vp-p Center of the waveform A (DC voltage) 0V Tracking servo Sled servo ON C (DC voltage) Tracking servo Sled servo OFF Checking Location: – CD BOARD (SIDE B) – TP4 (FE) TP2 (TE) TP5 (RFAC) TP7 (DVC) IC104 IC101 IC103 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 22 HCD-GP7 SECTION 7 DIAGRAMS Note on Schematic Diagram: • All capacitors are in µF unless otherwise noted. pF: µµF 50 WV or less are not indicated except for electrolytics and tantalums. • All resistors are in Ω and 1/4 W or less unless otherwise specified. • f : internal component. • 2 : nonflammable resistor. • 5 : fusible resistor. Note on Printed Wiring Boards: • X : parts extracted from the component side. • : Pattern from the side which enables seeing. (The other layers´ Patterns are not indicated.) Caution: Pattern face side: Parts on the pattern face side seen from the (Side B) pattern face are indicated. Parts face side: Parts on the parts face side seen from the (Side A) parts face are indicated. • Indication of transistor. • C : panel designation. • A : B+ Line. • B : B– Line. • H : adjustment for repair. • Voltages and waveforms are dc with respect to ground under no-signal conditions. • Voltages are taken with a VOM (Input impedance 10 MΩ). Voltage variations may be noted due to normal produc- tion tolerances. • Waveforms are taken with a oscilloscope. Voltage variations may be noted due to normal produc- tion tolerances. • Circled numbers refer to waveforms. • Signal path. F : TUNER (FM/AM) J : CD d : PLAYBACK G : RECORD h : MD Note: The components identified by mark 0 or dotted line with mark 0 are critical for safety. Replace only with part number specified. B These are omitted. C E Q B These are omitted. C E Q C B These are omitted. E Q www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 23 23 HCD-GP7 POWER-AMP board SUB-POWER board THR board SPEAKER board POWER board TC board MAIN board CD board LOADING board PANEL board HP board VOL board CIRCUIT BOARD LOCATION 3.0 Vp-p 30.5 s 2.8 Vp-p 1 V/DIV, 40 ns/DIV 62 ns 1 V/DIV, 10 s/DIV 4 IC401 qa (XCOUT) 5 IC401 qd (XOUT) – MAIN Board – • Waveforms – CD Board – 100 mV/DIV, 20 s/DIV 1 IC101 t; (RFAC)(CD Play mode) 200 mV/DIV, 400 ns/DIV 860mVp-p 2 IC101 ra (TE)(CD Play mode) 3 IC101 el (FE)(CD Play mode) 100 mV/DIV, 20 s/DIV 350mVp-p 250mVp-p 12.6 Vp-p 12.3 s 6 Q642 collector (TAPE REC mode) 5 V/DIV, 4 s/DIV – TC Board – 17.5Vp-p 5V/DIV, 4µs/DIV 9.9 µs 7 Q801 collector – PANEL Board – w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 24 24 HCD-GP7 7-1. Block Diagram — CD Section — : CD • Signal Path • R-CH is omitted due to same as L-CH OPTICAL PICK-UP BLOCK (KSM-213D) A B C D E F LD VC CD A+3.3V GND PD VR LD DRIVE FOCUS COIL TRACKING COIL Q101 RF AMP IC103 DVC 14 A 6 B 7 C 8 D 9 E 10 F 11 LD 1 PD 2 IC150 MOTOR/COIL DRIVE 18 17 12 11 M M101 SLED MOTOR M M102 SPINDLE MOTOR F+ F- T+ T- 2 20 25 27 MUTE MDP 25 SRDR 30 SFDR 29 TRDR 32 TFDR 31 FRDR 34 FFDR 33 DIGITAL SIGNAL PROC. IC101 DIGITAL SERVO RFAC 50 29 RFDCI 28 RFDCO 16 FE 17 FEI 12 SW RFDC 43 FE 39 TE 41 SE 40 66 PCMD 26 RO 4 DATA R-CH CD L-CH 6 CLOK 5 XLAT 77 SQCK 8 SCLK 15 SCOR 76 SQSO 26 SSTP 2 XRST S101 LIMIT IN SW CD-DATA 35 CD-CLK 37 XLAT 36 SQ-CLK 33 C-SCOR 19 SQ-DATA-IN 32 7 SENS SENS 56 IC401 (1/4) SYSTEM CONTROLLER 15 RF AC 18 TE CD +3.3V IC104 D/A CONV, MP3 DECODER SDIO 12 23 LO 67 BCLK BCKIA 13 65 LRCK LRCKIA 14 71 XTAI CKI/CKO 60 72 XTAO XI 62 XO 63 X201 16.9MHz 5 MIDIO 6 MICK 7 MIACK/AD2 39 PO7 1 RESET MP3 DATA IN 6 MP3 DATA OUT 5 MP3 CLK 7 78 3 MICS/AD0 MP3 CS 47 4 MILP/AD1 MP3 LP 48 MP3 ACK 49 MP3 RESET 46 MP3 REQ 45 XRST 60 BU PWM3 24 BU PWM2 26 BU PWM1 28 LDON 54 +2.5V REG 1 IC121 3 +2.5V CD A+3.3V A(CD)-MUTE Q101 MUTING Q303, 304 MUTING CONTROL LOAD-IN 68 67 LOAD-OUT OPEN 69 70 CLOSE 9 7 RIN FIN MOTOR DRIVE 2 4 OUT2 OUT1 IC311 MOTOR DRIVER M901 (LOADING) M A AMP SECTION APC DRV 22 23 + – DRV + – DRV DRV 15 16 4 14 13 6 7 + – 5 S1 (LEAF) Ver 1.1 2003.11 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 25 25 HCD-GP7 — TUNER/TAPE Section — • Signal path : PLAYBACK : RECORD : TUNER (FM/AM) • R-ch is omitted due to same as L-ch. TAPE PB-L C AMP SECTION TUNER L – CH B AMP SECTION REC-L D AMP SECTION DECK TC BLOCK Q642, 643 BIAS OSC Q641 RIPPLE FILTER R-CH FM/AM TUNER PACK ANTENNA L OUT FM ANT AM ANT AM ANT R OUT ST-MUTE STEREO TUNED ST-DOUT ST-DIN ST-CLK ST-CE FM 75Ω CAP M+ TRGM+ PACK F REC R REC PLAY SW END SW CAPM-CNT1 B TRG TC-RELAY B-HALF/REC SW B-PLAY B-SHUT-TC END SW BIAS ALC REC-MUTE TC-MUTE AM 60 EQ OUT A B 120 ST-MUTE STEREO TUNED ST-DIN ST-DOUT ST-CLK ST-CE BIAS TRAP REC BIAS(L) 37 9 8 7 4 3 4 5 7 10 42 80 41 40 90 38 91 43 TRIG DRIVE 58 CAP MOTOR DRIVE 59 34 21 57 27 22 25 23 12 11 15 14 Q680,681 BUFFER PB OUT TAI REC IN R-CH R-CH R-CH SW.P2 GND SW.R2 BIN RV653 C661, L651 TC A+9V IC602 REC/PB SWITCH REC/PB HEAD ERASE HEAD NORM/HIGH SPEED ALC ON/OFF REC MUTE ON/OFF MUTE ON/OFF IC601 PB/REC EQUALIZER AMP Q639,640 T601 Q691, 693 Q692,694 IC401 (2/4) SYSTEM CONTROLLER REC-OUT L – CH R – CH EQ RDS DATA RDA INT RDS DAT RDS INT 51 18 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 26 26 HCD-GP7 — AMP Section — IC321 POWER AMP • Signal Path • R-ch is omitted due to same as L-ch. : PLAYBACK : RECORD : TUNER (FM/AM) : CD : MD IC101 SOUND PROCESSOR Q121,221 MUTING Q328 SWITCH Q333 SWITCH Q322,323 MUTING CONTROL Q324 STANDBY SWITCH R-CH R-CH REC-L LCH SELO LCH OUT CD LCH CD L-CH MD(VIDEO) TUNER L-CH TAPE PB-L TUNER LCH TC LCH MD LCH EQ DATA EQ CLK J301 L 84 81 STK-POWER LIN-MUT 61 PROTECT 5 11 13 12 14 1 30 14 10 4 3 12 10 LCH IN 9 87 AMP(EQ) DATA Q329 PROTECT SWITCH + + + D371 D961 AC HI AC HI D962 Q122, 222 OVER LOAD DETECT + + Q321 MUTING CONTROL 66 FRONT-RELAY 50 HP DET Q334, 335 DC DETECT Q325,326 RELAY DRIVE Q331,332 RELAY SWITCH Q330 RELAY CONTROL + – + – SPEAKER IMPEDANCE USE 6-16Ω L R PHONES J321 RY801 IC401 (3/4) SYSTEM CONTROLLER TM801 D A B C 88 AMP(EQ) CLK EQ CE 2 86 AMP(EQ) CE CD SECTION TUNER/TAPE SECTION TUNER/TAPE SECTION TUNER/TAPE SECTION E DISPLAY/POWER SUPPLY SECTION Q371,372 FAN MOTOR DRIVE THP821 Q327 THERMAL DETECT R FAN 6 5 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 27 27 HCD-GP7 — DISPLAY/POWER SUPPLY Section — IC501 RESET SIGNAL GENERATOR FL801 FLUORESCENT INDICATOR TUBE SG1 – SG17 GR1 – GR11 53 VOLUME A 52 VOLUME B S851 ROTARY ENCODER VOLUME 32 – 42 14 – 29, 31 Q803 LED DRIVE IC801 FL DRIVER 1 FL SD 2 FL SCK 3 FL STB 7 DIN F1 F2 M +7V 8 CLK 9 30 STB VEE 4 SIRCS 44 STANDBY LED X401 16MHz 15 XIN 13 XOUT X402 32.768kHz 10 XCIN 11 XCOUT 65 CD-POWER IC401 (4/4) SYSTEM CONTROLLER 82 PWR-RELAY 12 RESET 20 AC-CUT Q301, 302 B+ SWITCH TC M+10V TC A+9V TUNER +9.4V IC101 VDD D305 D313 D304 EVER +3.3V RDS +3.3V TC +3.3V IC401 +3.3V D401 D402 D404 D403 D315 D302 D474 D475 D501 D957 – 960 RECT D912 – 915 RECT Q911 RELAY DRIVE D953 – 956 RECT T902 POWER TRANSFORMER (SUB) D901 RECT AMP B+ AMP B– AC HI AC HI AC HI AC HI AC LO AC LO RY911 (AC IN) T901 POWER TRANSFORMER (MAIN) Q501 RESET SWITCH Q801 - 802 DC/DC CONVERTER IC891 REMOTE CONTROL RECEIVER 1 97 1 3 1 3 1 3 IC304 +10V REG M +7V UNREG (L) 1 3 IC303 +7V REG 1 3 IC301 +4V REG IC911 +4V REG DD +3.3V RF +3.3V D301 D314 D891 (STBY) S801 – 805 FUNCTION KEY 95 S811 – 813 FUNCTION KEY 94 S821 – 826 FUNCTION KEY KEY0 KEY1 KEY2 74 POWER KEY E AMP SECTION w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 28 28 HCD-GP7 7-2. Printed Wiring Board — CD Section — • See page 23 for Circuit Boards Location. C150 C273 C260 C206 C292 C256 FB104 C255 C274 C250 R279 C263 R271 FB102 C269 C259 C262 C261 C265 FB107 C131 R151 C108 R215 R152 C224 Q101 C109 C202 R156 C132 C230 C117 R214 C222 FB291 C264 C158 C215 C118 C223 C216 R201 R276 C119 R202 C151 R203 R219 IC121 C226 C133 C113 C276 R123 R122 C114 FB103 C231 C229 C115 C111 R277 R280 C279 C275 1 2 3 E 11 (11) 1-686-782- CD BOARD (SIDE A) FB106 C249 R212 R254 CN101 R249 R259 R101 R255 R257 C271 R272 C266 R275 C257 C270 R251 R250 R216 C203 C253 C252 C267 R266 R265 C251 C268 R260 C227 X201 R204 R102 C209 R104 R126 R207 R118 C212 C211 R232 R153 R132 R252 R125 C102 R114 R103 R218 R117 R113 R105 IC150 C101 C254 R131 R155 IC103 C110 C103 IC101 IC104 C152 R133 R111 R206 R231 R205 C104 C258 C208 FB101 C116 C107 R213 R230 R220 R120 C213 R253 C205 CN102 L101 R233 CD BOARD (SIDE B) 11 (11) 1-686-782- OPTICAL PICK-UP BLOCK (KSM–213D) A 1 14 28 15 41 40 21 61 80 60 20 1 1 16 48 64 49 17 32 33 M102 SPINDLE MOTOR M101 SLED MOTOR M M S101 (LIMIT) 16 30 15 1 TP7(DVD) TP5(RFAC) TP2(TE) TP4(FE) TO MAIN BOARD CN306 (Page 32) 2 3 4 5 6 7 8 A 1 B C D E Ref. No. Location IC721 D-8 IC722 C-9 IC801 E-3 IC802 F-3 IC803 F-9 Q701 B-7 • Semiconductor Location Ver 1.1 2003.11 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 29 29 HCD-GP7 7-3. Schematic Diagram — CD Section — • See page 39, 40 for IC Block Diagrams. • See page 23 for Waveforms. IC104 IC101 IC121 IC103 IC150 R218 R205 R201 R103 R204 R202 C205 R206 R203 R104 X201 R105 R122 TP24 TP23 C104 TP22 TP21 TP2 TP3 TP4 TP9 R216 R215 R102 CN102 R118 R214 R250 R251 C260 C150 C158 TP1 R207 C223 C206 R252 TP25 TP26 TP27 TP28 TP5 TP6 TP7 TP8 C152 R220 R272 R271 R275 R257 R255 C256 C266 C264 R279 IC101 C103 C101 C202 TP16 TP13 TP12 TP17 C222 R113 R120 C151 R151 R152 TP10 TP11 TP14 TP18 TP19 TP20 TP15 R260 C273 C274 R259 R276 R213 R212 R254 R249 C269 C263 C249 R156 CN101 R123 R117 R111 R114 R253 C111 C115 R126 R277 R280 R231 R232 R233 R133 R132 R131 FB106 IC104 S101 LD PD FB291 0µH FB104 FB101 FB103 FB107 68µH L101 R125 R153 R155 C110 R219 C212 C211 R101 C250 C292 C255 C257 C270 C259 FB102 0µH 0µH 0µH C271 C258 C254 C253 R265 C267 C268 R266 C265 C262 C261 C251 C252 C227 C203 C229 C279 C275 C231 C208 C116 C117 C107 C102 C108 C131 C132 C133 C216 C215 C209 M101 M102 R230 C224 C230 C226 C213 C113 Q101 C114 C118 C276 C119 C109 IC150 IC121 IC103 1k 1k 33k 100k 2.2k 10k 0.1 F 2.2k 100k 10k 16.9M 1k 100k 3300p TE SE FE IOP 1M 0 10k 16P 10k 0 220 220 220 4V 100 10V 0.0022 B 1M 47 4V 47 4V 1M RFAC RFDC DVC MGND 0.1 F 1k 1k 10k 10k 100 100 0.1 0.1 F 47 4V 100 CXD3068Q 470p CH 470p CH 0.1 F C D E F 0.1 F 3.9k 120k 0.1 F 10k 220k VC VCC A AGND LD PD B 1k 220p B 10000p 100 100 470 470 100k 470 10 10V 10 10V 0.01 0 31P 3.3 120k 150k 390k 680 100 4V 220 4V 18k 0 0 100 100 100 2.2k 330k 68k CXD9717R-008 (LIMIT) 18k 0 0 0.1 1k 0.0022 0.1 0 0.1 1 0.1 0.33 220p 0.047 10000p 22p 22p 0.1 220 0.0022 0.0022 220 47 4V 47 4V 47 4V 0.1 0.1 0.1 0.001 0.1 1000 6.3V 220 4V 100 4V 0.1 0.1 0.1 22p 0.1 0.1 0.068 0.022 2.2 0.01 0.47 100p 220 0.1 0.1 47 4V 3300p 100 4V 2SB970 LD DRIVE 0.001 1 100 4V 1 0.1 BA5947FP BA25BCOFP +2.5V REG CXA2647 FD+ FD- TD- TD+ SQSO DATA XLAT CLOK SENS XRST SCOR SQCK SD+ SD- SP+ SP- SP- SP+ FD- FD+ SD+ SD- TD- TD+ FFDR FRDR PWM1 PWM2 PWM3 RFSW MDP SFDR SRDR TFDR TRDR FFDR FRDR MDP SFDR SRDR TFDR TRDR LRCK ADATA BCLK XCKO SDA/MIDIO SCL/MICK SDA/MIDIO PWM1 PWM2 PWM3 RFSW SQSO XRST DATA XLAT CLOK SENS SQCK SCOR MP3RST XRST MP3REQ SCL/MICK AMUTE/MIACK AMUTE/MIACK MP3RST MICS MILP MICS MILP MP3REQ XCKO ADATA BCLK LRCK DIGITAL SIGNAL PROCESSOR, DIGITAL SERVO, D/A CONV. MP3 DECODER MOTOR MOTOR SLED SPINDLE COIL TRACKING COIL FOCUS RF AMP 0µH 0µH 0µH MOTOR / COIL DRIVE TO MAIN BOARD CN306 (Page 33) No mark:CD PLAY (KSM-213D) Ver 1.1 2003.11 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 30 30 HCD-GP7 7-4. Printed Wiring Board — TC Section — • See page 23 for Circuit Boards Location. IC602 IC601 32 Ref. No. Location D681 C-4 IC601 B-2 IC602 A-2 Q639 C-4 Q640 B-3 Q641 B-3 Q642 A-4 Q643 B-4 Q680 B-3 Q681 B-3 Q691 C-3 Q692 C-3 Q693 C-4 Q694 C-3 • Semiconductor Location • : Uses unleaded solder. w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 31 31 HCD-GP7 7-5. Schematic Diagram — TC Section — • See page 23 for Waveforms. Q643 Q642 R645 R646 C641 RV603 RV653 R680 R606 R656 L601 L651 R651 R654 R652 R601 R604 R602 R605 R655 R632 R609 R659 C639 R660 R610 R611 R661 C606 C656 C634 C633 Q693 Q694 R641 C655 C651 C601 C635 C602 C605 C658 C608 R631 R630 C640 C663 IC602 R657 R607 R635 Q641 D681 R683 R685 R686 R687 R688 R689 R690 R692 R691 R695 R693 R694 L640 L641 R603 R653 R633 R640 JW630 JR602 R648 R647 Q691 Q692 Q639 RV602 R608 R658 Q680 T601 Q640 C611 C610 C614 C664 C660 C661 C662 C612 C642 C643 C644 C645 C646 R644 C647 R642 IC601 CN602 CN603 R682 R681 R684 C681 C607 C604 C652 C654 C657 C632 C630 C613 NO601 Q681 2SC2001 2SC2001 18k 18k 2.2 50V 220k 220k 4.7k 2.2k 2.2k 27mH 27mH 4.7k 10k 4.7k 4.7k 10k 4.7k 47k 47k 1k 2.2k 2.2k 10 50V 8.2k 8.2k 22k 22k 1 50V 1 50V 10 50V 10 50V 2SB1116 2SB1068 6.8k 10 50V 47 16V 47 16V 1 50V 0.01 PET 10 50V 2.2 50V 2.2 50V 22k 1M 47 16V 390p BA3126N 10k 10k 100 2SD1387-34-TP 1SS355TE 680 3.3k 3.3k 47k 4.7k 4.7k 4.7k 4.7k 10k 10k 47k 22k JW JW 3.3k 3.3k 10k 10k 0 0 2.2k 22k KRC102S-RTK KRC102S-RTK KTA1266-GR-AT XX NO MT 10k 10k KRC102M-AT KRC102M-AT 120p 330p 0.01 0.01 330p 120p 27p 27p 0.01 0.015 0.0068 0.0068 0.018 5.6 FR 10 50V 2.2k HA12237F 8P 19P 2.2k 2.2k 3.3k 0.0047 470p 0.1 0.01 0.1 470p 10 50V 100 16V 390p 8P DTA124ESA-TP w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 32 32 HCD-GP7 7-6. Printed Wiring Board — MAIN Section — • See page 23 for Circuit Boards Location. IC311 IC101 IC304 IC303 IC301 IC401 IC501 34 30 28 36 36 1 2 A B C D E F G H 3 4 5 6 7 8 9 M901 Ref. No. Location D301 F-7 D302 E-6 D304 D-7 D305 D-6 D311 C-8 D312 B-8 D313 C-7 D314 F-6 D315 E-4 D401 F-3 D402 F-3 D403 F-3 D404 F-3 D474 F-5 D475 F-5 D501 F-3 D502 F-3 D503 F-3 D504 G-4 IC101 D-8 IC301 F-7 IC303 F-7 IC304 E-7 IC311 B-3 IC401 G-4 IC501 G-3 Q101 C-5 Q201 C-5 Q301 F-6 Q302 F-6 Q303 C-5 Q304 C-5 Q501 F-4 • Semiconductor Location • : Uses unleaded solder. w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 33 33 HCD-GP7 7-7. Schematic Diagram — MAIN Section — • See page 41 for IC Block Diagrams. • See page 23 for Waveforms. IC101 X401 IC501 R401 R403 R404 R405 R406 R407 R419 R421 R422 R423 R425 R427 R432 R433 R434 R435 R436 R437 R438 R440 R441 R442 R443 R444 R445 R446 R447 R448 R449 R450 R451 R452 R453 R454 R456 R457 R458 R459 R460 R469 R491 C501 C312 R503 R504 C313 R420 R411 R501 D501 D504 R409 R502 R506 R554 R555 R556 R557 R562 R563 R564 C401 D474 R495 R497 R413 D475 R565 IC303 R402 D404 D402 R470 IC401 R101 C309 C310 C314 C315 IC301 R307 R308 CN307 R201 R204 R301 R302 R303 Q101 Q201 R107 R207 R105 R205 CN302 CN401 R430 R429 CN303 Q302 Q304 Q303 C301 C303 IC304 D311 D312 Q301 Q501 C302 C502 C503 FB302 FB306 C318 C322 C323 C324 C332 C402 C404 C405 C101 C102 C103 C104 C107 C105 C202 C203 C204 C205 D301 D305 R102 R202 R103 R203 C311 C351 D314 C241 C242 C243 C244 C245 C246 C247 C330 C331 C320 THP301 THP302 F301 C109 C110 C108 C319 C352 C326 CN301 R553 R480 R474 R566 R567 R461 R494 R490 R484 R482 R426 R424 R428 R591 R592 C406 C407 X402 C316 D302 D313 D315 D304 C106 C111 C209 C208 C207 C210 C211 C206 R206 D1 CN411 J301 CNJ304 FB307 FB308 C249 C248 C252 C250 C251 FB304 CN306 C112 C212 C254 C253 FB303 C333 C336 C201 D403 D502 R505 D503 D401 C317 C325 R106 CN1 M901 S1 R541 C321 R104 R544 R418 R417 IC311 LC75342 16MHz M62703SL 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 10 50V 0.1 50V 47k 47k 470 10V 4.7k 330k 220 1SS355TE 1SS355TE 10k 10k 10k 10k 10k 10k 10k 10k 10k 10k 1000 6.3V 1SS355TE 10 10 0 1SS355TE 10k TA7807S 100 1SS355TE 1SS355TE 100 M30624MGN-A18FP 10k 470 10V 0.1 50V 0.1 50V 470 10V 330 1k 5P 10k 1k 100 100 100 2SC3624 2SC3624 10k 10k 100k 100k 19P 17P 10k 10k 6P KRC102S-RTK KRC102S-RTK KRA102S-RTK 220 10V 100 10V 1SS355TE 1SS355TE RT1P137S KTC3199GR-RTK 0.1 0.1 0.1 0UH 0UH 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 220p TA7810S 1 50V 1 50V 1 50V 1 50V 10 50V 1 50V 1 50V 1 50V 10 50V 10EDB40 10EDB40 22k 22k 3.9k 3.9k 3300 25V 3300 16V 10EDB40 100p 100p 100p 100p 100p 100p 100p 0.1 F 0.1 F 0 RXE030 0 JW 0.068 50V 0.33 50V 1000 10V 1000 10V 0.0022 50V 0.1 F 15P 10k 100 1M 10k 10k 100 10 100 100 100 150k 2.7k 68k 100 100 15p 22p 32.768KHz 470 10V 1SS355TE 10EDB40 1SS355TE 10EDB40 1 50V 10 50V 0.068 0.0022 1 0.33 10 50V 1 50V 1k 0 4P 12P 0 0 100p 100p 100p 100p 100p 0UH 31P 10 50V 10 50V 100p 100p 0UH 470 10V 0.1 F 220p 1SS355TE 1SS355TE 4.7k 1SS355TE 1SS355TE 1000 10V 0.1 1k 5P 0 100 10V 1k 0 100 10k BA6956AN w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 34 34 HCD-GP7 7-8. Printed Wiring Board — PANEL Section — • See page 23 for Circuit Boards Location. IC891 IC801 32 1 2 A B C D E 3 4 5 6 7 8 Ref. No. Location D802 B-4 D803 B-4 D804 B-5 D805 B-5 D806 B-5 D891 C-8 IC801 B-6 IC891 B-8 Q801 B-4 Q802 B-4 Q803 C-8 • Semiconductor Location • : Uses unleaded solder. w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 35 35 HCD-GP7 7-9. Schematic Diagram — PANEL Section — • See page 42 for IC Block Diagrams. Q801 Q802 D806 IC891 S851 C860 C871 D891 Q803 C834 C835 C836 C837 C838 C839 C840 C841 C842 C844 C854 C857 C858 C861 C863 CN811 FB801 JR801 JR802 R807 R808 R809 R852 R861 R862 R863 R864 R881 R882 R883 R884 R885 S801 S802 S803 S804 S805 S811 S812 S813 S821 S822 S823 S824 S825 S826 C852 C853 C859 L801 C855 R854 R855 R853 R892 C891 R891 R893 C892 CN801 FL801 R830 C833 R805 C808 C809 R810 R811 C807 C862 C832 IC801 D802 D803 C856 D804 D805 T801 R871 R872 CNP811 2SD1624-T- TD 2SD1624-T- TD MA8047-H-TX RPM7240-H4 VR ENCORDER NM NM SLR-342VCT31 KRC102S-RTK 220p 50V B 220p 50V B 220p 50V B 220p 50V B 220p 50V B 220p 50V B 220p 50V B 220p 50V B 220p 50V B 0.01 50V F 10 50V 10 50V 0.1 16V F 10 50V 0.1 16V F 3P 0 0 1/10W 0 1/10W 100 1/10W 100 1/10W 100 1/10W 3.9k 1/10W 1k 1/10W 2.2k 1/10W 2.2k 1/10W 4.7k 1/10W 1k 1/10W 2.2k 1/10W 2.2k 1/10W 4.7k 1/10W 10k 1/10W 0.01 25V B 0.01 25V B NO MT 0.022 25V B 100 1/10W 100 1/10W 10k 47 0.01 47 470 10 50V 17P HNA-11SS50 1k 220p 82k 100p 0.001 100k 100k 0.001 0.1 16V F 220p PT6315 1SS133T-77 1SS133T-77 0.01 1SS133T-77 1SS133T-77 1k 2.2k w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 36 36 HCD-GP7 7-10. Printed Wiring Board — POWER AMP Section — • See page 23 for Circuit Boards Location. IC321 32 TO MAIN BOARD CNJ304 (Page 32) 38 1 2 A B C D E F G 3 4 5 6 7 8 9 10 11 Ref. No. Location D321 F-7 D322 F-8 D323 D-6 D324 D-6 D325 C-2 D326 D-7 D327 D-7 D328 D-7 D371 E-2 D953 A-8 D954 A-8 D955 A-8 D956 A-8 D957 A-7 D958 A-7 D959 A-7 D960 A-7 D961 A-6 D962 A-6 D963 A-5 IC321 G-6 Q121 G-8 Q122 D-6 Q221 G-7 Q222 D-7 Q321 F-7 Q322 F-7 Q323 F-8 Q324 F-6 Q325 C-5 Q326 D-5 Q327 D-8 Q328 D-7 Q329 C-8 Q330 C-7 Q331 C-7 Q332 C-6 Q333 D-7 Q334 D-6 Q335 D-7 Q371 E-2 Q372 E-2 • Semiconductor Location • : Uses unleaded solder. w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 37 37 HCD-GP7 7-11. Schematic Diagram — POWER AMP Section — (10.6) (10.6) (10) (0) (0.6) ( ) : Fan on D321 C354 D322 C353 D323 D324 D326 D327 C359 D328 C360 R129 R229 FB121 C142 C242 IC321 Q321 Q322 Q323 C122 C123 C222 C223 C361 C126 C127 C226 C227 C810 R125 R225 R228 R359 R126 R226 R361 R360 R373 R122 R222 R133 R233 R121 R123 R124 R221 R223 R224 R374 R375 R376 C352 C128 C129 C228 C229 C130 C230 R137 R237 R365 R363 R364 R367 C952 C358 C953 C954 R132 R232 R357 R131 R231 R369 R368 R366 R234 R134 R354 R355 R356 R370 R371 FB221 R241 C241 C141 R141 C121 C221 R352 R351 R353 C956 R130 R230 D953 D954 D955 D956 R127 R227 C355 C356 R381 R382 R383 R384 R385 C371 Q371 D371 Q372 D325 D957 D958 D959 D960 D963 C957 C958 R362 CN341 R358 CN992 C959 C124 C224 R386 CNJ321 CN961 CN971 CN972 CN343 CNJ951 Q221 Q121 EP321 R128 CNJ981 CNJ991 THP821 CN322 CNJ323 Q333 RY801 L221 L121 TM801 CN982 CNJ342 FAN CN962 EP951 Q222 Q122 Q325 C951 D962 D961 R952 R951 J321 CN311 Q324 Q327 Q328 Q330 Q329 Q331 Q332 Q334 Q335 Q326 1SS133T-77 10 50V 1SS133T-77 22 50V 1SS133T-77 1SS133T-77 1SS133T-77 1SS133T-77 100 10V 1SS133T-77 2.2 50V 0.22 2W 0.22 2W JW 0.001 0.001 STK403-070 KRA102M-AT KRA102M-AT KRC102M-AT 470p 470p 470p 470p 100 10V 0.01 50V 0.01 50V 0.01 50V 0.01 50V 0.01 16V 56k 56k 56k 4.7k 3.3k 3.3k 33k 10k 10k 100k 100k 10 1/2W 10 1/2W 2.2k 1k 1k 2.2k 1k 1k 2.2k 2.2k 220k 0.01 16V 0.1 50V 0.1 50V 0.1 50V 0.1 50V 0.01 16V 0.01 16V 10 1/2W 10 1/2W 2.2k 100k 100k 100k 2200 50V 10 50V 0.1 50V 0.1 50V 100k 100k 100k 15k 15k 22k 33k 4.7k 47k 56k 10k 10k 10k 10k 10k JW 470 2W 2.2 50V 2.2 50V 470 2W 10 50V 10 50V 1 1/4W 1 1/4W 100 1/4W 0.1 50V 1k 1k 10EDB40 10EDB40 10EDB40 10EDB40 2.2k 2.2k 22 50V 22 50V 47k 47k 10k 100k 2.2k 4.7 50V KTC3199GR 1SS133T-77 2SB1116 1SS133T-77 10EDB40 10EDB40 10EDB40 10EDB40 10EDB40 0.1 50V F 0.1 50V F 100k 3P 470 2W 2P 0.1 22 50V 22 50V 470k 6P 9P 6P 6P 2P 11P 2SC3623ATP-LK 2SC3623ATP-LK 56k 6P 2P 12P 4P KTA1266 GR-AT SP RELAY 6P 2P 9P KTA1266GR-AT KTA1266 GR-AT KTA1266GR-AT 2200 50V 1SS133T-77 1SS133T-77 1k 1k 4P KTC3199GR-TP KTC3199GR-TP KTC3199GR-TP KTC3199GR-TP KTC3199GR-TP KTC3199GR-TP KTC3199GR-TP KTC3199GR-TP KTC3199GR-TP KTC3199GR-TP w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 38 38 HCD-GP7 IC911 N 36 (SUB) 7-12. Printed Wiring Board — POWER Section — • See page 23 for Circuit Boards Location. 7-13. Schematic Diagram — POWER Section — Ref. No. Location D901 A-3 D911 B-2 D912 B-1 D913 B-1 D914 A-1 D915 A-1 IC911 A-2 Q911 A-2 • Semiconductor Location • : Uses unleaded solder. C902 C912 C913 D901 D911 IC911 Q911 R912 R913 JW4 JW5 R901 D912 D913 D914 D915 T901 JW6 JW7 C901 R911 CN901 T902 RY911 CN902 F904 F901 0.1 50V 1000 16V 100 10V D3SBA20-4101 1SS133T-77 KTC3199GR-TP 100k 47 0.1 1/4W 10EDB40 10EDB40 10EDB40 10EDB40 0.1 50V 4.7k 2P POWER RELAY 11P T2AL 250V T1AL 250V w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 39 HCD-GP7 7-14. IC Block Diagrams — CD Board — IC103 CXA2647N-T4 RW/ROM RW/ROM EQ ON/OFF VOFST VOFST DVC VC VC VC RW/ROM VC DVC 30 29 28 + – + – DVC VCC DVC 27 26 25 24 RW/ROM EQ 23 22 21 20 19 RFAC VCA VCC + – DVC + – + – RW/ROM VC RW/ROM DVC + – 3 A B C D B C A A A B C D B C D D + – 1 2 APC AMP 5 6 7 8 9 4 RFAC SUMMING AMP RW/ROM APC-OFF (Hi-Z) RW/ROM (H/L) VOFST VC RW/ROM + – 10 11 GM GM 18 17 16 B D A C 13 14 15 12 EQ IN LD PD GND A B C D AC SUM E F DVCC DVC RFAC SW DC OFST RFDCI RFDCO VC RFC VFC BST RFG VCC CEI CE TE BAL TE FEI FE www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 40 HCD-GP7 IC101 CXD3068Q CE RFDC ADIO IGEN ASYO ASYI RFAC CLTV FILO FILI PCO BIAS VCTL V16M VPCO TE ASYE MD2 DOUT LRCK PCMD BCK EMPH XTSL XTAI XTAO SOUT SOCK XOLT SQSO SQCK SCSY SBSO EXCK XRST MUTE DATA XLAT CLOK SENS SCLK ATSK WFCK XUGF XPCK GFS C2PO SCOR CAM WDCK COUT MIRR SE FE VC TES1 TEST FFDR TRDR TFDR SRDR SFDR FSTO SSTP LOCK PWMI FOK FRDR MDP DFCT CLOCK GENERATOR ASYMMETRY CORRECTOR DIGITAL PLL CPU INTERFACE INTERFACE CORRECTOR PROCESSOR SUB CODE RAM 32K DEMODURATOR EFM ERROR D/A DIGITAL OUT INTERFACE SERVO INTERFACE SERVO AUTO MIRR DFCT FOK SERVO FOCUS SERVO DSP SERVO SERVO SLED TRACKING FOCUS PWM GENERATOR GENERATOR GENERATOR SLED PWM TRACKING PWM A/D CONVERTER OPAMP ANALOG SW PWM GENERATOR DIGITAL CLV SERVO BLOCK www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 41 HCD-GP7 — MAIN Board — IC101 LC75342 CONTROL CIRCUIT LOGIC CIRCUIT CONTROL CIRCUIT CCB INTERFACE 1 2 3 4 5 6 7 8 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 15 14 13 12 11 10 9 DI CE VSS TEST LOUT LBASS2 LBASS1 LTRE LIN LSELO L4 L3 L2 L1 NC CL VDD VREF RVREF LVREF NC ROUT RBASS2 RBASS1 RTRE RIN RSELO R4 R3 R2 R1 NC IC311 BA6956AN 1 2 3 4 5 6 7 8 9 CONTROL LOGIC TSD VREF OUT2 OUT1 RNF VM VCC FIN GND RIN www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 42 HCD-GP7 — PANEL Board — IC801 PT6315 1 2 3 4 5 4-bit latch 24-bit output latch 12-bit shift register Data selector 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 Serial interface OSC Timing generator key scan Display memory 24 bits x 12 words Key data memory (2 x 16 bits) Command decoder segment driver Grid driver Multiplexed driver 39 40 41 42 43 44 LED1 LED2 LED3 LED4 OSC DOUT DIN CLK STB KEY1 KEY2 VSS VDD SEG1/KS1 SEG2/KS2 SEG3/KS3 SEG4/KS4 SEG5/KS5 SEG6/KS6 SEG7/KS7 SEG8/KS8 SEG9/KS9 SEG10/KS10 SEG20/GRID9 SEG21/GRID8 SEG22/GRID7 SEG23/GRID6 SEG24/GRID5 GRID4 GRID3 GRID2 GRID1 VDD VSS SEG11/KS11 SEG12/KS12 SEG13/KS13 SEG14/KS14 SEG15/KS15 SEG16/KS16 VEE SEG17/GRID12 SEG18/GRID11 SEG19/GRID10 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 43 HCD-GP7 7-15. IC Pin Function Description • IC104 CXD9717R-008 D/A Converter, MP3 Decoder (CD Board) Pin No. 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 to 34 35 36 37 38 39 40 41 42 43 44 45 46, 47 48 49, 50 51 52 53 I/O I I I I I/O I O – O O O I I I I I I – I – – – O – – O – – I O O – O O O O – I – I I – I – I I – I Pin Name RESET MIMD MICS/AD0 MILP/AD1 MIDIO MICK MIACK/AD2 VDDT SDO BCKO/AD3 LRCKO/AD4 SDI0 BCKIA LRCKIA SDI1/AD5 BCKIB/CE LRCKIB/OE VDD STANDBY VSS VSSL VRAL LO VDAL VDAR RO VRAR VSSR TESTP CSK PO0/AD12 to PO3/AD09 VDDT PO4/AD8 PO5/AD7 PO6/AD6 PO7 VSS FI0/AD13 FI1/AD14/VDDM FI2/WR FI3/AD16 VSSM PI0, PI1 VSS PI2/IO2, PI3/IO3 PI4/IO4 VDD PI5/IO5 Description Reset input terminal “L”: reset Microcomputer interface mode selection input “H”: I2C, “L”: TSB (fixed at “L”) Microcomputer interface chip select signal input Microcomputer interface latch pulse input Serial data input/output Serial clock input Microcomputer interface acknowledge signal output Power supply (3.3V) for digital circuit Data output (open) Bit output (open) LR clock output (open) Data input 0 Bit clock input A LR clock input A Data input 1 (fixed at “L”) Bit clock input B (fixed at “L”) LR clock input B (fixed at “L”) Power supply (2.5V) for digital circuit Standby mode control signal input “H”: STB, “L”: normal (fixed at “H”) Ground for digital circuit Ground for DAC Lch Reference voltage terminal for DAC Lch DAC Lch signal output Power supply (2.5V) for DAC Lch Power supply (2.5V) for DAC Rch DAC Rch signal output Reference voltage terminal for DAC Rch Ground for DAC Rch Terminal for test “H”: test mode, “L”: normal (fixed at “L”) SPDIF signal output (open) General purpose output (open) Power supply (3.3V) for digital circuit General purpose output (open) General purpose output (open) General purpose output (open) Interrupt request signal output to the system control Ground for digital circuit External interrupt signal input (fixed at “L”) Power supply (2.5V) for the internal 1Mbit SRAM Flag signal input 0 (fixed at “L”) Flag signal input 1 (fixed at “L”) Ground for the internal 1Mbit SRAM General purpose input (fixed at “L”) Ground for digital circuit General purpose input (fixed at “L”) General purpose input (fixed at “L”) Power supply (2.5V) for digital circuit General purpose input/SUBQ interface data input (fixed at “L”) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 44 HCD-GP7 Pin No. 54 55 56 57 58 59 60 61 62 63 64 I/O I I – O I – O – I O – Pin Name BOOT/IO6 TXO/IO7 VSSP PDO VCOI VDDP CKO VDDX XI XO VSSX Description Terminal for test/SUBQ interface frame sync input (fixed at “L”) Flag signal input 2/SUBQ interface block sync input (fixed at “L”) Ground for VCO circuit PLL phase error detection signal output VCO control voltage input Power supply (2.5V) for VCO circuit External clock output Power supply (2.5V) for oscillation circuit Resonator terminal (input) Resonator terminal (output) Ground for oscillation circuit www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 45 HCD-GP7 Pin No. 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 I/O O O O I O I O — — I O I O — I — I O I I O O O O I O O O I/O I/O I I O I O O O I O O O O O O I O O O I I Pin Name FL SD FL SCK FLSTB SIRCS MP3 DATA OUT MP3 DATA IN MP3 CLK BYTE CNVSS XCIN XCOUT RESET XOUT VSS XIN VCC NMI RDS-INT C-SCOR AC-CUT ST-MUTE ST-CE ST-DOUT BU PWM 3 ST-DIN BU PWM 2 ST-CLK BU PWM 1 IIC_CLK IIC_DATA CANNNOT USE SQ-DATA-IN SQ-CLK STEREO CD-DATA XLT CD-CLK B PLAY CLOCK OUT TC-MUTE REC-MUTE BAIS TC-RELAY STANDBY LED MP3 REQ MP3 RESET MP3 CS MP3 LP MP3 ACK HP DET Description Data output to the FL driver (IC801) Clock output to the FL driver (IC801) Strobe signal output to the FL driver (IC801) Remote control signal input from the remote control receiver (IC891) MP3 serial data output MP3 serial data input MP3 serial clock output Not used (fixed at “L”) Not used Sub system clock input (32.768kHz) Sub system clock output (32.768kHz) System reset signal input from the reset signal generator (IC501) Sysem clock output (16MHz) Ground terminal System clock input (16MHz) Power supply terminal Not used (fixed at “H”) RDS INT signal input Sub-code sync detection signal input AC cut detection signal input Tuner muting signal output Chip enable signal output to the tuner Data output to the tuner PWM signal output Data input from the tuner PWM signal output Clock output to the tuner PWM signal output Communication data clock input or output Communication data bus Not used (open) Subcode Q data input Subcode Q reading clock output Stereo detection signal input from the tuner Data output to the CD unit Latch signal output to the CD unit Clock output to the CD unit B PLAY switch signal input from the tape deck Not used (open) Tape line muting signal output (“H” : on, “L” : off) Tape record muting signal output (“H” : on, “L” : off) Bias on/off control signal output REC/PB switch control signal output to the IC602 Standby LED control signal output MP3 request signal input MP3 reset signal output MP3 chip select signal output MP3 latch signal output MP3 acknowledge signal input Headphone detection signal input • IC401 M30624MGN-A18FP System Controller (MAIN Board) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 46 HCD-GP7 Pin No. 51 52 53 54 55 56 57 58 59 60 61 62 63 64 65 66 67 68 69 70 71 to 73 74 75 to 77 78 79 80 81 82 83 84 85 86 87 88 89 90 91 92 93 94 95 96 97 98 99 100 I/O I I I O — I I O O O I – O — O O O O I I — I — O — O O O — O I O O O — I I I I I I — I — — — Pin Name RDS DATA VOLUME B VOLUME A LDON NC SENS TUNED B TRG CAPM-CNT1 XRST PROTECT VCC SOFT-TEST VSS CD-POWER FRONT-RELAY LOAD-OUT LOAD-IN OPEN CLOSE NC POWER KEY NC A(CD)-MUTE NC ALC LIN-MUT PWR-RELAY NC STK-POWER H/P MUTE AMP(EQ)-CE AMP(EQ)-DATA AMP(EQ)-CLK NC B SHUT-TC END SW B HALF/REC SW MODEL-IN SPEC-IN KEY2 KEY1 AVSS KEY0 VREF AVCC NC Description RDS data input Volume signal input from the rotary encoder Volume signal input from the rotary encoder Laser diode on/off control signal output Not used (open) Internal status monitor input from the CD unit Tuning detection signal input from the tuner Solenoid control signal output to the tape deck Capstan motor on/off control signal output CD reset signal output to the CD unit Protection signal input from the power amplifier circuit Power supply terminal Soft check output Ground terminal CD power supply control signal output Speaker relay on/off control signal output Loading motor control signal output to the motor driver (IC311) Loading motor control signal output to the motor driver (IC311) Open signal input from the S1 Close signal input from the S1 Not used (open) Key signal input from the POWER key Not used (open) CD DSP muting signal output Not used (open) ALC control signal output Line muting signal output Main power relay control signal output Not used (open) Standby control signal output to the power amplifier Not used (open) Chip enable signal output to the sound processor (IC101) Data output to the sound processor (IC101) Clock output to the sound processor (IC101) Not used (open) Shut off detection signal input from the reel pulse detector in the tape deck B half/rec switch detection signal input from the tape deck Model specification setting teminal Model destination setting terminal Key signal input Key signal input Ground terminal (analog) Key signal input Reference voltage input terminal (for A/D converter) Power supply terminal (analog) Not used (open) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com SECTION 8 EXPLODED VIEWS 47 HCD-GP7 NOTE: • -XX, -X mean standardized parts, so they may have some differences from the original one. • The mechanical parts with no reference number in the exploded views are not supplied. • Items marked “*” are not stocked since they are seldom required for routine service. Some delay should be anticipated when ordering these items. The components identified by mark 0 or dotted line with mark 0 are critical for safety. Replace only with part number specified. 1 4-247-752-01 RUBBER, FOOT 2 4-249-015-01 CASE,TOP 4 1-689-901-11 THR BOARD 5 1-689-610-11 POWER-AMP BOARD 6 1-698-792-11 FAN, DC 7 1-689-612-11 SPEAKER BOARD 8 1-693-626-11 TUNER (FM/AM) 9 1-773-009-11 WIRE (FLAT TYPE)(15 CORE) Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 10 A-4747-949-A MAIN BOARD, COMPLETE 11 4-247-367-01 LID,CD #1 7-685-872-01 SCREW +BVTT 3X8 #2 7-685-547-14 SCREW +BTT 3X8 #3 7-685-647-14 SCREW +BVTP 3X10 TYPE2 N-S #4 7-685-650-79 SCREW +BVTP 3X16 TYPE2 IT-3 #5 7-685-874-09 SCREW +BVTT 3X12 (S) #6 7-685-648-79 SCREW +BVTP 3X12 TYPE2 N-S 8-1. Over All Section not supplied not supplied not supplied not supplied not supplied not supplied not supplied not supplied 2 8 9 chassis section front panel section CD mechanism deck section #3 #3 #3 #3 #3 a b b a #3 #1 #6 #6 #1 #1 #1 #1 #1 #1 #1 #3 #3 #3 #2 #4 #5 #3 #3 7 11 4 5 10 1 6 #1 #1 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 48 HCD-GP7 Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 51 4-249-045-01 SPRING-T, CASSETTE 52 X-4955-862-1 LID ASSY, CASSETTE 53 4-247-372-01 HOLDER,CASSETTE 54 4-238-631-01 TAPE SPRING 55 4-247-361-01 COVER, DISPLAY 56 4-247-374-11 WINDOW,DISPLAY 57 4-247-366-11 CABINET,FRONT 58 4-247-376-01 POWER,INDICATER 59 4-247-370-11 BUTTON,POWER 60 4-247-368-11 BUTTON,FUNCTION 61 4-247-358-01 CAP, CD 62 4-247-359-01 CAP, TUNING 63 4-249-019-01 KNOB,VOLUME 64 4-247-360-11 COVER, RING 65 1-689-613-11 HP BOARD 66 4-247-369-11 BUTTON,OPEN/CLOSE 67 4-247-371-11 BUTTON,CD 68 4-231-841-01 SPRING (HEART CAM-B) 69 4-231-825-01 CAM (B), HEART 70 4-224-104-41 DAMPER 71 4-247-752-01 RUBBER, FOOT 72 4-249-020-01 RING,VOLUME 73 1-796-351-51 MECHANISM, SIGNAL CASSETTE 74 A-4747-951-A TC BOARD, COMPLETE 75 1-773-114-11 WIRE (FLAT TYPE)(19 CORE) 76 4-247-357-11 CAP, AUX 77 A-4747-952-A PANEL BOARD, COMPLETE 78 4-249-984-01 FILTER, FL TUBE 79 4-917-583-71 BRACKET, YOKE 80 1-689-608-11 VOL BOARD 81 4-249-823-01 HOLDER, LED 82 4-249-151-01 HOLDER (FL TUBE) 83 1-773-038-11 WIRE (FLAT TYPE)(17 CORE) 84 1-824-335-11 WIRE (FLAT TYPE)(8 CORE) FL801 1-518-909-11 INDICATOR TUBE, FLUORESCENT #3 7-685-647-14 SCREW +BVTP 3X10 TYPE2 N-S #7 7-685-647-79 SCREW +BVTP 3X10 TYPE2 N-S #8 7-685-533-19 SCREW +BTP 2.6X6 8-2. Front Panel Section 51 52 53 54 55 56 57 58 59 76 61 62 63 64 65 FL801 66 67 68 69 70 71 72 73 74 75 84 60 77 81 80 83 82 78 79 not supplied not supplied not supplied #3 #7 #8 #7 #7 #7 #3 #3 #8 #8 #3 #3 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 49 HCD-GP7 101 4-900-386-01 SCREW 0102 1-769-744-52 CORD, POWER 104 1-689-611-11 SUB-POWER BOARD 105 3-970-608-11 SUMITITE (B3), +BV 106 4-247-752-01 RUBBER, FOOT 108 3-703-244-00 BUSHING (2104), CORD 0F901 1-533-465-11 FUSE, GLASS TUBE (DIA. 5)(T1AL/250V) 0F904 1-533-468-11 FUSE, GLASS TUBE (DIA. 5)(T2AL/250V) 0T901 1-443-037-11 POWER TRANSFORMER #1 7-685-872-01 SCREW +BVTT 3X8 Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 8-3. Chassis Section not supplied T901 #1 F901 F904 not supplied 107 101 104 105 108 106 102 The components identified by mark 0 or dotted line with mark 0 are critical for safety. Replace only with part number specified. Ver 1.1 2003.11 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 50 HCD-GP7 Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 151 1-674-336-12 LOADING BOARD 152 4-925-315-31 DAMPER 153 4-224-894-22 TRAY (CDM55D) 154 4-220-233-01 CAM (CDM55) 155 4-221-815-11 ROLLER 156 4-220-237-01 GEAR (A) 157 4-220-234-01 PULLEY (LDG) 158 4-221-816-01 BELT (CDM55) 159 4-227-598-01 SPACER (55) 160 4-220-238-01 GEAR (B) 161 4-220-229-02 LEVER (SW) 162 4-220-239-01 SPRING, TORSION 163 A-4731-446-A CD BOARD, COMPLETE 164 A-473-508-2A MAGNET 165 4-231-777-02 SHEET (KH2) 166 4-244-962-01 HOLDER (C213) 167 4-985-672-01 SCREW (+PTPWH M2.6), FLOATING 168 4-229-358-01 SHAFT (BU21) 169 4-227-549-11 INSULATOR 170 4-244-959-01 SPRING (T213), COMPRESSION 171 4-231-151-01 STOPPER (BU) 172 4-218-253-31 SCREW (M2.6), +BTTP 173 1-782-817-11 WIRE (FLAT TYPE)(16 CORE) M901 A-4735-337-A MOTOR (LD) ASSY (LOADING) #9 7-685-533-19 SCREW +BTP 2.6X6 TYPE2 N-S #10 7-621-255-32 SCREW +P 2X5 8-4. CD Mechanism Section M901 #9 #10 151 152 153 154 155 156 157 158 160 159 161 162 166 167 164 165 168 169 171 170 170 172 163 170 167 173 171 169 169 169 not supplied not supplied not supplied optical pick-up (BU-K6BD47S) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 51 HCD-GP7 Ref. No. Part No. Description Remark 8-5. KSM-213D 601 0601 A-4735-357-A BASE ASSY, OP (KSM-213D) The components identified by mark 0 or dotted line with mark 0 are critical for safety. Replace only with part number specified. Ver 1.1 2003.11 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com SECTION 9 ELECTRICAL PARTS LIST 52 HCD-GP7 NOTE: • Due to standardization, replacements in the parts list may be different from the parts speci- fied in the diagrams or the components used on the set. • -XX and -X mean standardized parts, so they may have some difference from the original one. • RESISTORS All resistors are in ohms. METAL: Metal-film resistor. METAL OXIDE: Metal oxide-film resistor. F: nonflammable • Items marked “*” are not stocked since they are seldom required for routine service. Some delay should be anticipated when order- ing these items. • SEMICONDUCTORS In each case, u: µ, for example: uA. . : µA. . uPA. . : µPA. . uPB. . : µPB. . uPC. . : µPC. . uPD. . : µPD. . • CAPACITORS uF: µF • COILS uH: µH Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks When indicating parts by reference number, please include the board name. The components identified by mark 0 or dotted line with mark 0 are critical for safety. Replace only with part number specified. A-4731-446-A CD BOARD, COMPLETE ******************* < CAPACITOR > C101 1-164-315-11 CERAMIC CHIP 470PF 5.00% 50V C102 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V C103 1-164-315-11 CERAMIC CHIP 470PF 5.00% 50V C104 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V C107 1-162-919-11 CERAMIC CHIP 22PF 5% 50V C108 1-164-360-11 CERAMIC CHIP 0.1uF 16V C109 1-164-360-11 CERAMIC CHIP 0.1uF 16V C110 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V C111 1-126-209-11 ELECT CHIP 100uF 20.00% 4V C113 1-126-209-11 ELECT CHIP 100uF 20.00% 4V C114 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C115 1-126-246-11 ELECT CHIP 220uF 20% 4V C116 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V C117 1-164-360-11 CERAMIC CHIP 0.1uF 16V C118 1-115-156-11 CERAMIC CHIP 1uF 10V C119 1-115-156-11 CERAMIC CHIP 1uF 10V C131 1-110-563-11 CERAMIC CHIP 0.068uF 10.00% 16V C132 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V C133 1-125-838-11 CERAMIC CHIP 2.2uF 10% 6.3V C150 1-128-995-21 ELECT CHIP 100uF 20% 10V C151 1-164-360-11 CERAMIC CHIP 0.1uF 16V C152 1-164-360-11 CERAMIC CHIP 0.1uF 16V C158 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V C202 1-164-360-11 CERAMIC CHIP 0.1uF 16V C203 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C205 1-164-360-11 CERAMIC CHIP 0.1uF 16V C206 1-126-607-11 ELECT CHIP 47uF 20% 4V C208 1-164-360-11 CERAMIC CHIP 0.1uF 16V C209 1-162-927-11 CERAMIC CHIP 100PF 5% 50V C211 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V C212 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V C213 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V C215 1-117-863-11 CERAMIC CHIP 0.47uF 10.00% 6.3V C216 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C222 1-164-360-11 CERAMIC CHIP 0.1uF 16V C223 1-126-607-11 ELECT CHIP 47uF 20% 4V C224 1-164-360-11 CERAMIC CHIP 0.1uF 16V C226 1-126-607-11 ELECT CHIP 47uF 20% 4V C227 1-164-360-11 CERAMIC CHIP 0.1uF 16V C229 1-164-360-11 CERAMIC CHIP 0.1uF 16V C230 1-164-360-11 CERAMIC CHIP 0.1uF 16V C231 1-126-209-11 ELECT CHIP 100uF 20.00% 4V C249 1-162-974-11 CERAMIC CHIP 0.01uF 50V C250 1-164-360-11 CERAMIC CHIP 0.1uF 16V C251 1-164-360-11 CERAMIC CHIP 0.1uF 16V C252 1-164-360-11 CERAMIC CHIP 0.1uF 16V C253 1-164-360-11 CERAMIC CHIP 0.1uF 16V C254 1-162-919-11 CERAMIC CHIP 22PF 5% 50V C255 1-164-360-11 CERAMIC CHIP 0.1uF 16V C256 1-164-360-11 CERAMIC CHIP 0.1uF 16V C257 1-165-112-11 CERAMIC CHIP 0.33uF 16V C258 1-162-919-11 CERAMIC CHIP 22PF 5% 50V C259 1-164-361-11 CERAMIC CHIP 0.047uF 16V C260 1-126-246-11 ELECT CHIP 220uF 20% 4V C261 1-126-607-11 ELECT CHIP 47uF 20% 4V C262 1-126-607-11 ELECT CHIP 47uF 20% 4V C263 1-125-822-11 TANTAL. CHIP 10uF 20% 10V C264 1-126-607-11 ELECT CHIP 47uF 20% 4V C265 1-126-607-11 ELECT CHIP 47uF 20% 4V C266 1-164-360-11 CERAMIC CHIP 0.1uF 16V C267 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V C268 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V C269 1-125-822-11 TANTAL. CHIP 10uF 20% 10V C270 1-162-960-11 CERAMIC CHIP 220PF 10% 50V C271 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C273 1-162-960-11 CERAMIC CHIP 220PF 10% 50V C274 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C275 1-126-246-11 ELECT CHIP 220uF 20% 4V C276 1-126-209-11 ELECT CHIP 100uF 20.00% 4V C279 1-100-588-21 ELECT CHIP 1000uF 20% 6.3V C292 1-115-156-11 CERAMIC CHIP 1uF 10V < CONNECTOR > CN101 1-784-387-11 CONNECTOR, FFC/FPC 31P CN102 1-777-937-11 CONNECTOR, FFC/FPC 16P < FERRITE BEAD > FB101 1-500-283-11 FERRITE 0uH FB102 1-500-283-11 FERRITE 0uH FB103 1-500-283-11 FERRITE 0uH FB104 1-500-283-11 FERRITE 0uH FB106 1-500-283-11 FERRITE 0uH FB107 1-500-283-11 FERRITE 0uH FB291 1-500-283-11 FERRITE 0uH < IC > IC101 8-752-408-73 IC CXD3068Q CD www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 53 HCD-GP7 Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks IC103 8-752-106-21 IC CXA2647N-T4 IC104 6-704-150-01 IC CXD9717R-008 IC121 6-700-394-01 IC BA25BC0FP-E2 IC150 8-759-677-90 IC BA5947FP-E2 < COIL > L101 1-412-063-21 INDUCTOR 68uH < TRANSISTOR > Q101 8-729-046-90 TRANSISTOR 2SB970-(TX).S0 < RESISTOR > R101 1-216-864-11 METAL CHIP 0 5% 1/10W R102 1-216-833-11 METAL CHIP 10K 5% 1/10W R103 1-216-845-11 METAL CHIP 100K 5% 1/10W R104 1-216-833-11 METAL CHIP 10K 5% 1/10W R105 1-216-821-11 METAL CHIP 1K 5% 1/10W R111 1-216-847-11 METAL CHIP 150K 5% 1/10W R113 1-216-828-11 METAL CHIP 3.9K 5% 1/10W R114 1-216-852-11 METAL CHIP 390K 5% 1/10W R117 1-216-846-11 METAL CHIP 120K 5% 1/10W R118 1-216-833-11 METAL CHIP 10K 5% 1/10W R120 1-216-846-11 METAL CHIP 120K 5% 1/10W R122 1-216-845-11 METAL CHIP 100K 5% 1/10W R123 1-216-791-11 METAL CHIP 3.3 5% 1/10W R125 1-216-836-11 METAL CHIP 18K 5% 1/10W R126 1-216-836-11 METAL CHIP 18K 5% 1/10W R131 1-216-843-11 METAL CHIP 68K 5% 1/10W R132 1-216-851-11 METAL CHIP 330K 5% 1/10W R133 1-216-825-11 METAL CHIP 2.2K 5% 1/10W R151 1-216-833-11 METAL CHIP 10K 5% 1/10W R152 1-216-849-11 METAL CHIP 220K 5% 1/10W R153 1-216-864-11 METAL CHIP 0 5% 1/10W R155 1-216-864-11 METAL CHIP 0 5% 1/10W R156 1-216-864-11 METAL CHIP 0 5% 1/10W R201 1-216-839-11 METAL CHIP 33K 5% 1/10W R202 1-216-833-11 METAL CHIP 10K 5% 1/10W R203 1-216-845-11 METAL CHIP 100K 5% 1/10W R204 1-216-825-11 METAL CHIP 2.2K 5% 1/10W R205 1-216-821-11 METAL CHIP 1K 5% 1/10W R206 1-216-825-11 METAL CHIP 2.2K 5% 1/10W R207 1-216-857-11 METAL CHIP 1M 5% 1/10W R212 1-216-817-11 METAL CHIP 470 5% 1/10W R213 1-216-817-11 METAL CHIP 470 5% 1/10W R214 1-216-864-11 METAL CHIP 0 5% 1/10W R215 1-216-864-11 METAL CHIP 0 5% 1/10W R216 1-216-857-11 METAL CHIP 1M 5% 1/10W R218 1-216-821-11 METAL CHIP 1K 5% 1/10W R219 1-216-821-11 METAL CHIP 1K 5% 1/10W R220 1-216-821-11 METAL CHIP 1K 5% 1/10W R230 1-216-813-11 METAL CHIP 220 5% 1/10W R231 1-216-809-11 METAL CHIP 100 5% 1/10W R232 1-216-809-11 METAL CHIP 100 5% 1/10W R233 1-216-809-11 METAL CHIP 100 5% 1/10W R249 1-216-817-11 METAL CHIP 470 5% 1/10W R250 1-216-813-11 METAL CHIP 220 5% 1/10W R251 1-216-813-11 METAL CHIP 220 5% 1/10W R252 1-216-857-11 METAL CHIP 1M 5% 1/10W R253 1-216-819-11 METAL CHIP 680 5% 1/10W R254 1-216-845-11 METAL CHIP 100K 5% 1/10W R255 1-216-809-11 METAL CHIP 100 5% 1/10W R257 1-216-809-11 METAL CHIP 100 5% 1/10W R259 1-216-809-11 METAL CHIP 100 5% 1/10W R260 1-216-821-11 METAL CHIP 1K 5% 1/10W R265 1-216-813-11 METAL CHIP 220 5% 1/10W R266 1-216-813-11 METAL CHIP 220 5% 1/10W R271 1-216-833-11 METAL CHIP 10K 5% 1/10W R272 1-216-821-11 METAL CHIP 1K 5% 1/10W R275 1-216-833-11 METAL CHIP 10K 5% 1/10W R276 1-216-809-11 METAL CHIP 100 5% 1/10W R277 1-216-864-11 METAL CHIP 0 5% 1/10W R279 1-216-809-11 METAL CHIP 100 5% 1/10W R280 1-216-296-11 SHORT CHIP 0 < SWITCH > S101 1-771-853-11 SWITCH, DETECTION (LIMIT) < VIBRATOR > X201 1-767-408-21 VIBRATOR, CRYSTAL (16.9MHz) ************************************************************ 1-689-613-11 HP BOARD ********* < CAPACITOR > C142 1-162-294-31 CERAMIC 0.001uF 10% 50V C242 1-162-294-31 CERAMIC 0.001uF 10% 50V < CONNECTOR > * CN311 1-564-720-11 PIN, CONNECTOR (SMALL TYPE) 4P < JACK > J321 1-816-219-11 JACK, HEADPHONE (PHONES) ************************************************************ 1-674-336-12 LOADING BOARD ************** < CONNECTOR > * CN151 1-568-943-11 PIN, CONNECTOR 5P < SWITCH > S1 1-786-203-11 SWITCH, LEVER (SLIDE)(OPEN/CLOSE) ************************************************************ A-4747-949-A MAIN BOARD, COMPLETE ********************* < CAPACITOR > C101 1-162-957-11 CERAMIC CHIP 220PF 5% 50V C102 1-115-871-11 ELECT 1uF 20.00% 50V C103 1-115-871-11 ELECT 1uF 20.00% 50V C104 1-115-871-11 ELECT 1uF 20.00% 50V C105 1-126-795-11 ELECT 10uF 20.00% 50V HP CD LOADING MAIN www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 54 HCD-GP7 Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks C106 1-115-871-11 ELECT 1uF 20.00% 50V C107 1-115-871-11 ELECT 1uF 20.00% 50V C108 1-130-475-00 MYLAR 0.0022uF 5% 50V C109 1-137-375-11 MYLAR 0.068uF 5.00% 50V C110 1-136-171-00 FILM 0.33uF 5.00% 50V C111 1-126-795-11 ELECT 10uF 20.00% 50V C112 1-126-964-11 ELECT 10uF 20.00% 50V C201 1-162-957-11 CERAMIC CHIP 220PF 5% 50V C202 1-115-871-11 ELECT 1uF 20.00% 50V C203 1-115-871-11 ELECT 1uF 20.00% 50V C204 1-115-871-11 ELECT 1uF 20.00% 50V C205 1-126-795-11 ELECT 10uF 20.00% 50V C206 1-115-871-11 ELECT 1uF 20.00% 50V C207 1-115-871-11 ELECT 1uF 20.00% 50V C208 1-130-475-00 MYLAR 0.0022uF 5% 50V C209 1-137-375-11 MYLAR 0.068uF 5.00% 50V C210 1-136-171-00 FILM 0.33uF 5.00% 50V C211 1-126-795-11 ELECT 10uF 20.00% 50V C212 1-126-964-11 ELECT 10uF 20.00% 50V C241 1-162-927-11 CERAMIC CHIP 100PF 5% 50V C242 1-162-927-11 CERAMIC CHIP 100PF 5% 50V C243 1-162-927-11 CERAMIC CHIP 100PF 5% 50V C244 1-162-927-11 CERAMIC CHIP 100PF 5% 50V C245 1-162-927-11 CERAMIC CHIP 100PF 5% 50V C246 1-162-927-11 CERAMIC CHIP 100PF 5% 50V C247 1-162-927-11 CERAMIC CHIP 100PF 5% 50V C248 1-162-927-11 CERAMIC CHIP 100PF 5% 50V C249 1-162-927-11 CERAMIC CHIP 100PF 5% 50V C250 1-162-927-11 CERAMIC CHIP 100PF 5% 50V C251 1-162-927-11 CERAMIC CHIP 100PF 5% 50V C252 1-162-927-11 CERAMIC CHIP 100PF 5% 50V C253 1-162-927-11 CERAMIC CHIP 100PF 5% 50V C254 1-162-927-11 CERAMIC CHIP 100PF 5% 50V C301 1-126-176-11 ELECT 220uF 20% 10V C302 1-164-156-11 CERAMIC CHIP 0.1uF 25V C303 1-124-584-00 ELECT 100uF 20% 10V C309 1-126-935-11 ELECT 470uF 20.00% 10V C310 1-126-956-91 ELECT 0.1uF 20.00% 50V C311 1-126-944-11 ELECT 3300uF 20.00% 25V C312 1-126-956-91 ELECT 0.1uF 20.00% 50V C313 1-126-935-11 ELECT 470uF 20.00% 10V C314 1-126-956-91 ELECT 0.1uF 20.00% 50V C315 1-126-935-11 ELECT 470uF 20.00% 10V C316 1-126-935-11 ELECT 470uF 20.00% 10V C317 1-126-926-11 ELECT 1000uF 20.00% 10V C318 1-164-156-11 CERAMIC CHIP 0.1uF 25V C319 1-126-926-11 ELECT 1000uF 20.00% 10V C320 1-216-864-11 METAL CHIP 0 5% 1/10W C321 1-104-665-11 ELECT 100uF 20.00% 10V C322 1-164-156-11 CERAMIC CHIP 0.1uF 25V C323 1-164-156-11 CERAMIC CHIP 0.1uF 25V C324 1-164-156-11 CERAMIC CHIP 0.1uF 25V C325 1-164-156-11 CERAMIC CHIP 0.1uF 25V C326 1-164-156-11 CERAMIC CHIP 0.1uF 25V C330 1-164-156-11 CERAMIC CHIP 0.1uF 25V C331 1-164-156-11 CERAMIC CHIP 0.1uF 25V C332 1-164-156-11 CERAMIC CHIP 0.1uF 25V C333 1-126-935-11 ELECT 470uF 20.00% 10V C336 1-164-156-11 CERAMIC CHIP 0.1uF 25V C351 1-126-936-11 ELECT 3300uF 20.00% 16V C352 1-126-926-11 ELECT 1000uF 20.00% 10V C401 1-126-916-11 ELECT 1000uF 20.00% 6.3V C402 1-164-156-11 CERAMIC CHIP 0.1uF 25V C404 1-164-156-11 CERAMIC CHIP 0.1uF 25V C405 1-164-156-11 CERAMIC CHIP 0.1uF 25V C406 1-162-917-11 CERAMIC CHIP 15PF 5% 50V C407 1-162-919-11 CERAMIC CHIP 22PF 5% 50V C501 1-126-964-11 ELECT 10uF 20.00% 50V C502 1-130-495-00 MYLAR 0.1uF 5% 50V C503 1-130-495-00 MYLAR 0.1uF 5% 50V < CONNECTOR > CN301 1-784-776-11 CONNECTOR, FFC 15P CN302 1-784-780-11 CONNECTOR, FFC 19P * CN303 1-564-708-11 PIN, CONNECTOR (SMALL TYPE) 6P CN306 1-779-299-11 CONNECTOR,FFC(LIF(NON-ZIF))31P CN307 1-564-707-11 PIN, CONNECTOR (SMALL TYPE) 5P CN401 1-784-778-11 CONNECTOR, FFC 17P < DIODE > D1 1-216-864-11 METAL CHIP 0 5% 1/10W D301 6-500-522-21 DIODE 10EDB40-TB3 D302 8-719-988-61 DIODE 1SS355TE-17 D304 6-500-522-21 DIODE 10EDB40-TB3 D305 6-500-522-21 DIODE 10EDB40-TB3 D311 8-719-988-61 DIODE 1SS355TE-17 D312 8-719-988-61 DIODE 1SS355TE-17 D313 6-500-522-21 DIODE 10EDB40-TB3 D314 6-500-522-21 DIODE 10EDB40-TB3 D315 8-719-988-61 DIODE 1SS355TE-17 D401 8-719-988-61 DIODE 1SS355TE-17 D402 8-719-988-61 DIODE 1SS355TE-17 D403 8-719-988-61 DIODE 1SS355TE-17 D404 8-719-988-61 DIODE 1SS355TE-17 D474 8-719-988-61 DIODE 1SS355TE-17 D475 8-719-988-61 DIODE 1SS355TE-17 D501 8-719-988-61 DIODE 1SS355TE-17 D502 8-719-988-61 DIODE 1SS355TE-17 D503 8-719-988-61 DIODE 1SS355TE-17 D504 8-719-988-61 DIODE 1SS355TE-17 < FERRITE BEAD/RESISTOR > FB302 1-414-772-11 FERRITE 0uH FB303 1-414-772-11 FERRITE 0uH FB304 1-414-772-11 FERRITE 0uH FB306 1-414-772-11 FERRITE 0uH FB307 1-216-864-11 METAL CHIP 0 5% 1/10W FB308 1-216-864-11 METAL CHIP 0 5% 1/10W < IC > IC101 8-759-669-03 IC LC75342 IC301 6-701-760-01 IC uPC3504AHF IC303 8-759-071-48 IC TA7807S IC304 8-759-231-57 IC TA7810S IC311 8-759-598-69 IC BA6956AN MAIN www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 55 HCD-GP7 Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks IC401 6-803-046-01 IC M30624MGN-A18FP IC501 8-759-532-64 IC M62703SL-TP < JACK > J301 1-764-593-21 JACK 2P (MD(VIDEO)) < TRANSISTOR > Q101 8-729-107-43 TRANSISTOR 2SC3624-T1L1718 Q201 8-729-107-43 TRANSISTOR 2SC3624-T1L1718 Q301 8-729-049-79 TRANSISTOR RT1P137S-TP Q302 8-729-038-67 TRANSISTOR KRC102S Q303 8-729-038-54 TRANSISTOR KRA102S Q304 8-729-038-67 TRANSISTOR KRC102S Q501 8-729-016-42 TRANSISTOR KTC3199GR-TP < RESISTOR > R101 1-216-833-11 METAL CHIP 10K 5% 1/10W R102 1-216-837-11 METAL CHIP 22K 5% 1/10W R103 1-216-828-11 METAL CHIP 3.9K 5% 1/10W R104 1-216-821-11 METAL CHIP 1K 5% 1/10W R105 1-216-845-11 METAL CHIP 100K 5% 1/10W R106 1-216-821-11 METAL CHIP 1K 5% 1/10W R107 1-216-833-11 METAL CHIP 10K 5% 1/10W R201 1-216-833-11 METAL CHIP 10K 5% 1/10W R202 1-216-837-11 METAL CHIP 22K 5% 1/10W R203 1-216-828-11 METAL CHIP 3.9K 5% 1/10W R204 1-216-821-11 METAL CHIP 1K 5% 1/10W R205 1-216-845-11 METAL CHIP 100K 5% 1/10W R206 1-216-821-11 METAL CHIP 1K 5% 1/10W R207 1-216-833-11 METAL CHIP 10K 5% 1/10W R301 1-216-809-11 METAL CHIP 100 5% 1/10W R302 1-216-809-11 METAL CHIP 100 5% 1/10W R303 1-216-809-11 METAL CHIP 100 5% 1/10W R307 1-216-815-11 METAL CHIP 330 5% 1/10W R308 1-216-821-11 METAL CHIP 1K 5% 1/10W R401 1-216-809-11 METAL CHIP 100 5% 1/10W R402 1-216-809-11 METAL CHIP 100 5% 1/10W R403 1-216-809-11 METAL CHIP 100 5% 1/10W R404 1-216-809-11 METAL CHIP 100 5% 1/10W R405 1-216-809-11 METAL CHIP 100 5% 1/10W R406 1-216-809-11 METAL CHIP 100 5% 1/10W R407 1-216-809-11 METAL CHIP 100 5% 1/10W R409 1-216-833-11 METAL CHIP 10K 5% 1/10W R411 1-216-851-11 METAL CHIP 330K 5% 1/10W R413 1-216-864-11 METAL CHIP 0 5% 1/10W R417 1-216-833-11 METAL CHIP 10K 5% 1/10W R418 1-216-809-11 METAL CHIP 100 5% 1/10W R419 1-216-809-11 METAL CHIP 100 5% 1/10W R420 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R421 1-216-809-11 METAL CHIP 100 5% 1/10W R422 1-216-809-11 METAL CHIP 100 5% 1/10W R423 1-216-809-11 METAL CHIP 100 5% 1/10W R424 1-216-826-11 METAL CHIP 2.7K 5% 1/10W R425 1-216-809-11 METAL CHIP 100 5% 1/10W R426 1-216-847-11 METAL CHIP 150K 5% 1/10W R427 1-216-809-11 METAL CHIP 100 5% 1/10W R428 1-216-843-11 METAL CHIP 68K 5% 1/10W R429 1-216-833-11 METAL CHIP 10K 5% 1/10W R430 1-216-833-11 METAL CHIP 10K 5% 1/10W R432 1-216-809-11 METAL CHIP 100 5% 1/10W R433 1-216-809-11 METAL CHIP 100 5% 1/10W R434 1-216-809-11 METAL CHIP 100 5% 1/10W R435 1-216-809-11 METAL CHIP 100 5% 1/10W R436 1-216-809-11 METAL CHIP 100 5% 1/10W R437 1-216-809-11 METAL CHIP 100 5% 1/10W R438 1-216-809-11 METAL CHIP 100 5% 1/10W R440 1-216-809-11 METAL CHIP 100 5% 1/10W R441 1-216-809-11 METAL CHIP 100 5% 1/10W R442 1-216-809-11 METAL CHIP 100 5% 1/10W R443 1-216-809-11 METAL CHIP 100 5% 1/10W R444 1-216-809-11 METAL CHIP 100 5% 1/10W R445 1-216-809-11 METAL CHIP 100 5% 1/10W R446 1-216-809-11 METAL CHIP 100 5% 1/10W R447 1-216-809-11 METAL CHIP 100 5% 1/10W R448 1-216-809-11 METAL CHIP 100 5% 1/10W R449 1-216-809-11 METAL CHIP 100 5% 1/10W R450 1-216-809-11 METAL CHIP 100 5% 1/10W R451 1-216-809-11 METAL CHIP 100 5% 1/10W R452 1-216-809-11 METAL CHIP 100 5% 1/10W R453 1-216-809-11 METAL CHIP 100 5% 1/10W R454 1-216-809-11 METAL CHIP 100 5% 1/10W R456 1-216-809-11 METAL CHIP 100 5% 1/10W R457 1-216-809-11 METAL CHIP 100 5% 1/10W R458 1-216-809-11 METAL CHIP 100 5% 1/10W R459 1-216-809-11 METAL CHIP 100 5% 1/10W R460 1-216-809-11 METAL CHIP 100 5% 1/10W R461 1-216-809-11 METAL CHIP 100 5% 1/10W R469 1-216-809-11 METAL CHIP 100 5% 1/10W R470 1-216-809-11 METAL CHIP 100 5% 1/10W R474 1-216-857-11 METAL CHIP 1M 5% 1/10W R480 1-216-809-11 METAL CHIP 100 5% 1/10W R482 1-216-809-11 METAL CHIP 100 5% 1/10W R484 1-216-809-11 METAL CHIP 100 5% 1/10W R490 1-216-809-11 METAL CHIP 100 5% 1/10W R491 1-216-809-11 METAL CHIP 100 5% 1/10W R494 1-216-797-11 METAL CHIP 10 5% 1/10W R495 1-216-797-11 METAL CHIP 10 5% 1/10W R497 1-216-797-11 METAL CHIP 10 5% 1/10W R501 1-216-813-11 METAL CHIP 220 5% 1/10W R502 1-216-833-11 METAL CHIP 10K 5% 1/10W R503 1-216-841-11 METAL CHIP 47K 5% 1/10W R504 1-216-841-11 METAL CHIP 47K 5% 1/10W R505 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R506 1-216-833-11 METAL CHIP 10K 5% 1/10W R541 1-216-864-11 METAL CHIP 0 5% 1/10W R544 1-216-864-11 METAL CHIP 0 5% 1/10W R553 1-216-833-11 METAL CHIP 10K 5% 1/10W R554 1-216-833-11 METAL CHIP 10K 5% 1/10W R555 1-216-833-11 METAL CHIP 10K 5% 1/10W R556 1-216-833-11 METAL CHIP 10K 5% 1/10W R557 1-216-833-11 METAL CHIP 10K 5% 1/10W R562 1-216-833-11 METAL CHIP 10K 5% 1/10W R563 1-216-833-11 METAL CHIP 10K 5% 1/10W R564 1-216-833-11 METAL CHIP 10K 5% 1/10W R565 1-216-833-11 METAL CHIP 10K 5% 1/10W MAIN www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 56 HCD-GP7 Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks PANEL R566 1-216-833-11 METAL CHIP 10K 5% 1/10W R567 1-216-833-11 METAL CHIP 10K 5% 1/10W R591 1-216-809-11 METAL CHIP 100 5% 1/10W R592 1-216-809-11 METAL CHIP 100 5% 1/10W < THERMISTOR(POSITIVE) > THP301 1-804-046-11 THERMISTOR, POSITIVE (RXE030) THP302 1-216-296-11 SHORT CHIP 0 < VIBRATOR > X401 1-781-107-21 VIBRATOR, SERAMIC (16MHz) X402 1-567-098-41 VIBRATOR, CRYSTAL (32.768kHz) ************************************************************ A-4747-952-A PANEL BOARD, COMPLETE ********************** 4-249-151-01 HOLDER (FL TUBE) 4-249-823-01 HOLDER, LED < CAPACITOR > C807 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C808 1-162-927-11 CERAMIC CHIP 100PF 5% 50V C809 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C832 1-162-960-11 CERAMIC CHIP 220PF 10% 50V C833 1-162-960-11 CERAMIC CHIP 220PF 10% 50V C834 1-162-960-11 CERAMIC CHIP 220PF 10% 50V C835 1-162-960-11 CERAMIC CHIP 220PF 10% 50V C836 1-162-960-11 CERAMIC CHIP 220PF 10% 50V C837 1-162-960-11 CERAMIC CHIP 220PF 10% 50V C838 1-162-960-11 CERAMIC CHIP 220PF 10% 50V C839 1-162-960-11 CERAMIC CHIP 220PF 10% 50V C840 1-162-960-11 CERAMIC CHIP 220PF 10% 50V C841 1-162-960-11 CERAMIC CHIP 220PF 10% 50V C842 1-162-960-11 CERAMIC CHIP 220PF 10% 50V C844 1-162-974-11 CERAMIC CHIP 0.01uF 50V C854 1-124-261-00 ELECT 10uF 20% 50V C855 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V C856 1-162-974-11 CERAMIC CHIP 0.01uF 50V C857 1-126-795-11 ELECT 10uF 20.00% 50V C858 1-164-360-11 CERAMIC CHIP 0.1uF 16V C861 1-124-261-00 ELECT 10uF 20% 50V C862 1-164-360-11 CERAMIC CHIP 0.1uF 16V C863 1-164-360-11 CERAMIC CHIP 0.1uF 16V C891 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C892 1-126-795-11 ELECT 10uF 20.00% 50V < CONNECTOR > CN801 1-784-739-11 CONNECTOR, FFC 17P * CN811 1-564-719-11 PIN, CONNECTOR (SMALL TYPE) 3P < DIODE > D802 8-719-991-33 DIODE 1SS133T-77 D803 8-719-991-33 DIODE 1SS133T-77 D804 8-719-991-33 DIODE 1SS133T-77 D805 8-719-991-33 DIODE 1SS133T-77 D806 8-719-976-96 DIODE MA8047-H-TX D891 8-719-059-98 DIODE SLR-342VCT31 ( ?/1 ) < FERRITE BEAD > FB801 1-216-295-91 SHORT CHIP 0 < FLUORESCENT INDICATOR TUBE > FL801 1-518-909-11 INDICATOR TUBE, FLUORESCENT < IC > IC801 8-759-643-83 IC PT6315 IC891 6-600-174-01 IC RPM7240-H4 (g) < JUMPER RESISTOR > JR801 1-216-864-11 METAL CHIP 0 5% 1/10W JR802 1-216-864-11 METAL CHIP 0 5% 1/10W < COIL > L801 1-410-671-31 INDUCTOR 47uH < TRANSISTOR > Q801 8-729-808-42 TRANSISTOR 2SD1624-T-TD Q802 8-729-808-42 TRANSISTOR 2SD1624-T-TD Q803 8-729-038-67 TRANSISTOR KRC102S < RESISTOR > R805 1-216-844-11 METAL CHIP 82K 5% 1/10W R807 1-216-809-11 METAL CHIP 100 5% 1/10W R808 1-216-809-11 METAL CHIP 100 5% 1/10W R809 1-216-809-11 METAL CHIP 100 5% 1/10W R810 1-216-845-11 METAL CHIP 100K 5% 1/10W R811 1-216-845-11 METAL CHIP 100K 5% 1/10W R830 1-216-821-11 METAL CHIP 1K 5% 1/10W R852 1-216-828-11 METAL CHIP 3.9K 5% 1/10W R853 1-216-833-11 METAL CHIP 10K 5% 1/10W R854 1-216-809-11 METAL CHIP 100 5% 1/10W R855 1-216-809-11 METAL CHIP 100 5% 1/10W R861 1-216-821-11 METAL CHIP 1K 5% 1/10W R862 1-216-825-11 METAL CHIP 2.2K 5% 1/10W R863 1-216-825-11 METAL CHIP 2.2K 5% 1/10W R864 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R871 1-216-821-11 METAL CHIP 1K 5% 1/10W R872 1-216-825-11 METAL CHIP 2.2K 5% 1/10W R881 1-216-821-11 METAL CHIP 1K 5% 1/10W R882 1-216-825-11 METAL CHIP 2.2K 5% 1/10W R883 1-216-825-11 METAL CHIP 2.2K 5% 1/10W R884 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R885 1-216-833-11 METAL CHIP 10K 5% 1/10W R891 1-216-805-11 METAL CHIP 47 5% 1/10W R892 1-216-805-11 METAL CHIP 47 5% 1/10W R893 1-216-817-11 METAL CHIP 470 5% 1/10W < SWITCH > S801 1-786-050-21 SWITCH, KEY BOARD ( ?/1 ) S802 1-786-050-21 SWITCH, KEY BOARD (TUNER/BAND) S803 1-786-050-21 SWITCH, KEY BOARD (CD u ) S804 1-786-050-21 SWITCH, KEY BOARD (TAPE b B ) S805 1-786-050-21 SWITCH, KEY BOARD (Z) S811 1-786-050-21 SWITCH, KEY BOARD (z REC PAUSE/START) MAIN www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 57 HCD-GP7 Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks S812 1-786-050-21 SWITCH, KEY BOARD (CD SYNC) S813 1-786-050-21 SWITCH, KEY BOARD (x) S821 1-786-050-21 SWITCH, KEY BOARD (MD) S822 1-786-050-21 SWITCH, KEY BOARD (TUNING +) S823 1-786-050-21 SWITCH, KEY BOARD (TUNING -) S824 1-786-050-21 SWITCH, KEY BOARD (PLAY MODE/TUNING MODE DIRECTION) S825 1-786-050-21 SWITCH, KEY BOARD (REPEAT/FM MODE) S826 1-786-050-21 SWITCH, KEY BOARD (DSG) < TRANSFORMER > T801 1-443-056-11 TRANSFORMER, DC-DC CONVERTER ************************************************************ 1-689-609-11 POWER BOARD ************* < CAPACITOR > C901 1-136-165-00 FILM 0.1uF 5.00% 50V C902 1-136-165-00 FILM 0.1uF 5.00% 50V C912 1-126-767-11 ELECT 1000uF 20.00% 16V C913 1-124-584-00 ELECT 100uF 20% 10V < CONNECTOR > CN901 1-564-321-00 PIN, CONNECTOR(3.96MM PITCH)2P * CN902 1-764-334-11 PLUG, CONNECTOR 11P < DIODE > D901 8-719-028-23 DIODE D3SBA20-4101 D911 8-719-991-33 DIODE 1SS133T-77 D912 6-500-522-01 DIODE 10EDB40-TA1B2 D913 6-500-522-01 DIODE 10EDB40-TA1B2 D914 6-500-522-01 DIODE 10EDB40-TA1B2 D915 6-500-522-01 DIODE 10EDB40-TA1B2 FH901 1-533-233-31 FUSE HOLDER FH902 1-533-233-31 FUSE HOLDER FH903 1-533-233-31 FUSE HOLDER FH904 1-533-233-31 FUSE HOLDER < IC > IC911 6-701-760-01 IC uPC3504AHF < TRANSISTOR > Q911 8-729-016-42 TRANSISTOR KTC3199GR-TP < RESISTOR > 0R901 1-219-119-81 FUSIBLE 0.1 5% 1/4W R911 1-249-425-11 CARBON 4.7K 5% 1/4W F R912 1-249-441-11 CARBON 100K 5% 1/4W R913 1-249-401-11 CARBON 47 5% 1/4W F < RELAY > 0RY911 1-755-332-11 RELAY < TRANSFORMER > 0T902 1-437-730-11 TRANSFORMER, POWER ************************************************************ 1-689-610-11 POWER-AMP BOARD ***************** < CAPACITOR > C121 1-126-964-11 ELECT 10uF 20.00% 50V C122 1-162-290-31 CERAMIC 470PF 10% 50V C123 1-162-290-31 CERAMIC 470PF 10% 50V C124 1-126-965-91 ELECT 22uF 20.00% 50V C126 1-136-153-00 FILM 0.01uF 5% 50V C127 1-136-153-00 FILM 0.01uF 5% 50V C221 1-126-964-11 ELECT 10uF 20.00% 50V C222 1-162-290-31 CERAMIC 470PF 10% 50V C223 1-162-290-31 CERAMIC 470PF 10% 50V C224 1-126-965-91 ELECT 22uF 20.00% 50V C226 1-136-153-00 FILM 0.01uF 5% 50V C227 1-136-153-00 FILM 0.01uF 5% 50V C352 1-162-306-11 CERAMIC 0.01uF 30.00% 16V C353 1-126-965-91 ELECT 22uF 20.00% 50V C354 1-126-964-11 ELECT 10uF 20.00% 50V C355 1-126-965-91 ELECT 22uF 20.00% 50V C356 1-126-965-91 ELECT 22uF 20.00% 50V C810 1-162-306-11 CERAMIC 0.01uF 30.00% 16V < DIODE > D321 8-719-991-33 DIODE 1SS133T-77 D322 8-719-991-33 DIODE 1SS133T-77 < TERMINAL > EP321 1-537-770-21 TERMINAL BOARD, GROUND < IC > IC321 6-600-089-01 IC STK403-070 < TRANSISTOR > Q121 8-729-141-30 TRANSISTOR 2SC3623ATP-LK Q221 8-729-141-30 TRANSISTOR 2SC3623ATP-LK Q321 8-729-037-29 TRANSISTOR KRA102M-AT Q322 8-729-037-29 TRANSISTOR KRA102M-AT Q323 8-729-036-58 TRANSISTOR KRC102M-AT Q324 8-729-016-42 TRANSISTOR KTC3199GR-TP < RESISTOR > R121 1-249-421-11 CARBON 2.2K 5% 1/4W F R122 1-249-441-11 CARBON 100K 5% 1/4W R123 1-249-417-11 CARBON 1K 5% 1/4W F R124 1-249-417-11 CARBON 1K 5% 1/4W F R125 1-249-438-11 CARBON 56K 5% 1/4W R126 1-247-843-11 CARBON 3.3K 5% 1/4W R127 1-249-421-11 CARBON 2.2K 5% 1/4W F R128 1-249-438-11 CARBON 56K 5% 1/4W 0R129 1-220-755-11 METAL 0.22 10% 2W R133 1-260-076-11 CARBON 10 5% 1/2W R221 1-249-421-11 CARBON 2.2K 5% 1/4W F R222 1-249-441-11 CARBON 100K 5% 1/4W R223 1-249-417-11 CARBON 1K 5% 1/4W F R224 1-249-417-11 CARBON 1K 5% 1/4W F The components identified by mark 0 or dotted line with mark 0 are critical for safety. Replace only with part number specified. PANEL POWER POWER-AMP www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 58 HCD-GP7 Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks R225 1-249-438-11 CARBON 56K 5% 1/4W R226 1-247-843-11 CARBON 3.3K 5% 1/4W R227 1-249-421-11 CARBON 2.2K 5% 1/4W F R228 1-249-438-11 CARBON 56K 5% 1/4W 0R229 1-220-755-11 METAL 0.22 10% 2W R233 1-260-076-11 CARBON 10 5% 1/2W 0R351 1-202-972-61 FUSIBLE 1 5% 1/4W 0R352 1-202-972-61 FUSIBLE 1 5% 1/4W 0R353 1-212-881-11 FUSIBLE 100 5% 1/4W R359 1-249-425-11 CARBON 4.7K 5% 1/4W F R360 1-249-429-11 CARBON 10K 5% 1/4W R361 1-249-435-11 CARBON 33K 5% 1/4W R373 1-249-429-11 CARBON 10K 5% 1/4W R374 1-249-421-11 CARBON 2.2K 5% 1/4W F R375 1-249-421-11 CARBON 2.2K 5% 1/4W F R376 1-247-887-00 CARBON 220K 5% 1/4W ************************************************************ 1-689-612-11 SPEAKER BOARD ************** < CAPACITOR > C128 1-164-159-21 CERAMIC 0.1uF 50V C129 1-164-159-21 CERAMIC 0.1uF 50V C130 1-162-306-11 CERAMIC 0.01uF 30.00% 16V C228 1-164-159-21 CERAMIC 0.1uF 50V C229 1-164-159-21 CERAMIC 0.1uF 50V C230 1-162-306-11 CERAMIC 0.01uF 30.00% 16V C371 1-126-963-11 ELECT 4.7uF 20.00% 50V < CONNECTOR > CN341 1-564-506-11 PLUG, CONNECTOR 3P CN982 1-564-509-11 PLUG, CONNECTOR 6P < DIODE > D325 8-719-991-33 DIODE 1SS133T-77 D371 8-719-991-33 DIODE 1SS133T-77 < COIL > L121 1-422-009-13 COIL, AIR-CORE L221 1-422-009-13 COIL, AIR-CORE < TRANSISTOR > Q371 8-729-016-42 TRANSISTOR KTC3199GR-TP Q372 8-729-140-04 TRANSISTOR 2SB1116-TP-LK < RESISTOR > R137 1-260-076-11 CARBON 10 5% 1/2W R237 1-260-076-11 CARBON 10 5% 1/2W R381 1-249-437-11 CARBON 47K 5% 1/4W R382 1-249-437-11 CARBON 47K 5% 1/4W R383 1-249-429-11 CARBON 10K 5% 1/4W R384 1-249-441-11 CARBON 100K 5% 1/4W R385 1-249-421-11 CARBON 2.2K 5% 1/4W F < RELAY > RY801 1-515-920-11 RELAY (24V) < TERMINAL > TM801 1-536-708-81 TERMINAL BOARD, PUSH (4P)(SPEAKER) ************************************************************ 1-689-611-11 SUB-POWER BOARD ***************** < CAPACITOR > C141 1-109-953-11 ELECT 2.2uF 20.00% 50V C241 1-109-953-11 ELECT 2.2uF 20.00% 50V C358 1-126-964-11 ELECT 10uF 20.00% 50V C359 1-104-665-11 ELECT 100uF 20.00% 10V C360 1-126-961-11 ELECT 2.2uF 20.00% 50V C361 1-104-665-11 ELECT 100uF 20.00% 10V C951 1-128-550-11 ELECT 2200uF 20.00% 50V C952 1-128-550-11 ELECT 2200uF 20.00% 50V C953 1-136-165-00 FILM 0.1uF 5.00% 50V C954 1-136-165-00 FILM 0.1uF 5.00% 50V C956 1-164-159-21 CERAMIC 0.1uF 50V C957 1-136-165-00 FILM 0.1uF 5.00% 50V C958 1-136-165-00 FILM 0.1uF 5.00% 50V C959 1-136-165-00 FILM 0.1uF 5.00% 50V < CONNECTOR > * CN322 1-564-714-11 PIN, CONNECTOR (SMALL TYPE)12P * CN343 1-564-704-11 PIN, CONNECTOR (SMALL TYPE) 2P * CN962 1-564-711-11 PIN, CONNECTOR (SMALL TYPE) 9P CN972 1-564-509-11 PLUG, CONNECTOR 6P < DIODE > D323 8-719-991-33 DIODE 1SS133T-77 D324 8-719-991-33 DIODE 1SS133T-77 D326 8-719-991-33 DIODE 1SS133T-77 D327 8-719-991-33 DIODE 1SS133T-77 D328 8-719-991-33 DIODE 1SS133T-77 D953 6-500-522-01 DIODE 10EDB40-TA1B2 D954 6-500-522-01 DIODE 10EDB40-TA1B2 D955 6-500-522-01 DIODE 10EDB40-TA1B2 D956 6-500-522-01 DIODE 10EDB40-TA1B2 D957 6-500-522-01 DIODE 10EDB40-TA1B2 D958 6-500-522-01 DIODE 10EDB40-TA1B2 D959 6-500-522-01 DIODE 10EDB40-TA1B2 D960 6-500-522-01 DIODE 10EDB40-TA1B2 D961 8-719-991-33 DIODE 1SS133T-77 D962 8-719-991-33 DIODE 1SS133T-77 D963 6-500-522-01 DIODE 10EDB40-TA1B2 < TERMINAL > EP951 1-537-738-21 TERMINAL, GROUND < TRANSISTOR > Q122 8-729-037-03 TRANSISTOR KTA1266GR-AT Q222 8-729-037-03 TRANSISTOR KTA1266GR-AT Q325 8-729-037-03 TRANSISTOR KTA1266GR-AT Q326 8-729-016-42 TRANSISTOR KTC3199GR-TP Q327 8-729-016-42 TRANSISTOR KTC3199GR-TP The components identified by mark 0 or dotted line with mark 0 are critical for safety. Replace only with part number specified. SPEAKER SUB-POWER POWER-AMP www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 59 HCD-GP7 Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks Q328 8-729-016-42 TRANSISTOR KTC3199GR-TP Q329 8-729-016-42 TRANSISTOR KTC3199GR-TP Q330 8-729-016-42 TRANSISTOR KTC3199GR-TP Q331 8-729-016-42 TRANSISTOR KTC3199GR-TP Q332 8-729-016-42 TRANSISTOR KTC3199GR-TP Q333 8-729-037-03 TRANSISTOR KTA1266GR-AT Q334 8-729-016-42 TRANSISTOR KTC3199GR-TP Q335 8-729-016-42 TRANSISTOR KTC3199GR-TP < RESISTOR > R130 1-249-417-11 CARBON 1K 5% 1/4W F R131 1-249-431-11 CARBON 15K 5% 1/4W R132 1-249-441-11 CARBON 100K 5% 1/4W R134 1-249-438-11 CARBON 56K 5% 1/4W 0R141 1-215-890-11 METAL OXIDE 470 5% 2W R230 1-249-417-11 CARBON 1K 5% 1/4W F R231 1-249-431-11 CARBON 15K 5% 1/4W R232 1-249-441-11 CARBON 100K 5% 1/4W R234 1-249-437-11 CARBON 47K 5% 1/4W 0R241 1-215-890-11 METAL OXIDE 470 5% 2W R354 1-249-429-11 CARBON 10K 5% 1/4W R355 1-249-429-11 CARBON 10K 5% 1/4W R356 1-249-429-11 CARBON 10K 5% 1/4W R357 1-249-441-11 CARBON 100K 5% 1/4W 0R358 1-215-890-11 METAL OXIDE 470 5% 2W R362 1-249-441-11 CARBON 100K 5% 1/4W R363 1-249-441-11 CARBON 100K 5% 1/4W R364 1-249-441-11 CARBON 100K 5% 1/4W R365 1-249-421-11 CARBON 2.2K 5% 1/4W F R366 1-249-425-11 CARBON 4.7K 5% 1/4W F R367 1-249-441-11 CARBON 100K 5% 1/4W R368 1-249-435-11 CARBON 33K 5% 1/4W R369 1-249-433-11 CARBON 22K 5% 1/4W R370 1-249-429-11 CARBON 10K 5% 1/4W R371 1-249-429-11 CARBON 10K 5% 1/4W R386 1-247-895-91 CARBON 470K 5% 1/4W R951 1-249-417-11 CARBON 1K 5% 1/4W F R952 1-249-417-11 CARBON 1K 5% 1/4W F ************************************************************ A-4747-951-A TC BOARD, COMPLETE ******************* < CAPACITOR > C601 1-126-947-11 ELECT 47uF 20.00% 16V C602 1-130-483-00 MYLAR 0.01uF 5% 50V C604 1-130-495-00 MYLAR 0.1uF 5% 50V C605 1-126-964-11 ELECT 10uF 20.00% 50V C606 1-126-960-11 ELECT 1uF 20.00% 50V C607 1-162-962-11 CERAMIC CHIP 470PF 10% 50V C608 1-126-961-11 ELECT 2.2uF 20.00% 50V C610 1-162-961-11 CERAMIC CHIP 330PF 10% 50V C611 1-162-928-11 CERAMIC CHIP 120PF 5% 50V C612 1-162-946-11 CERAMIC CHIP 27PF 5% 50V C613 1-164-392-11 CERAMIC CHIP 390PF 10.00% 50V C614 1-130-483-00 MYLAR 0.01uF 5% 50V C630 1-126-933-11 ELECT 100uF 20.00% 16V C632 1-126-964-11 ELECT 10uF 20.00% 50V C633 1-126-964-11 ELECT 10uF 20.00% 50V C634 1-126-964-11 ELECT 10uF 20.00% 50V C635 1-126-960-11 ELECT 1uF 20.00% 50V C639 1-126-964-11 ELECT 10uF 20.00% 50V C640 1-126-947-11 ELECT 47uF 20.00% 16V C641 1-126-961-11 ELECT 2.2uF 20.00% 50V C642 1-137-150-11 MYLAR 0.01uF 5.00% 100V C643 1-130-485-00 MYLAR 0.015uF 5% 50V C644 1-130-481-00 MYLAR 0.0068uF 5% 50V C645 1-130-481-00 MYLAR 0.0068uF 5% 50V C646 1-130-486-00 MYLAR 0.018uF 10% 50V C647 1-126-964-11 ELECT 10uF 20.00% 50V C651 1-126-947-11 ELECT 47uF 20.00% 16V C652 1-130-483-00 MYLAR 0.01uF 5% 50V C654 1-130-495-00 MYLAR 0.1uF 5% 50V C655 1-126-964-11 ELECT 10uF 20.00% 50V C656 1-126-960-11 ELECT 1uF 20.00% 50V C657 1-162-962-11 CERAMIC CHIP 470PF 10% 50V C658 1-126-961-11 ELECT 2.2uF 20.00% 50V C660 1-162-961-11 CERAMIC CHIP 330PF 10% 50V C661 1-162-928-11 CERAMIC CHIP 120PF 5% 50V C662 1-162-946-11 CERAMIC CHIP 27PF 5% 50V C663 1-164-392-11 CERAMIC CHIP 390PF 10.00% 50V C664 1-130-483-00 MYLAR 0.01uF 5% 50V C681 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V < CONNECTOR > CN602 1-770-516-31 CONNECTOR, FFC 8P CN603 1-784-780-11 CONNECTOR, FFC 19P < DIODE > D681 8-719-988-61 DIODE 1SS355TE-17 < IC > IC601 6-702-130-01 IC HA12237F IC602 8-759-508-69 IC BA3126N < JUMPER RESISTOR > JR602 1-216-296-11 SHORT CHIP 0 < JUMPER RESISTOR > JW630 1-216-864-11 METAL CHIP 0 5% 1/10W < COIL > L601 1-410-780-11 INDUCTOR 27MH L651 1-410-780-11 INDUCTOR 27MH < TRANSISTOR > Q639 8-729-037-03 TRANSISTOR KTA1266GR-AT Q640 8-729-036-58 TRANSISTOR KRC102M-AT Q641 8-729-801-93 TRANSISTOR 2SD1387-34-TP Q642 8-729-142-46 TRANSISTOR 2SC2001TP-LK Q643 8-729-142-46 TRANSISTOR 2SC2001TP-LK Q680 8-729-036-58 TRANSISTOR KRC102M-AT Q681 8-729-029-40 TRANSISTOR DTA124ESA-TP Q691 8-729-038-67 TRANSISTOR KRC102S Q692 8-729-038-67 TRANSISTOR KRC102S SUB-POWER TC The components identified by mark 0 or dotted line with mark 0 are critical for safety. Replace only with part number specified. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 60 HCD-GP7 Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks Q693 8-729-140-04 TRANSISTOR 2SB1116-TP-LK Q694 8-729-116-57 TRANSISTOR 2SB1068TP-K < RESISTOR > R601 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R602 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R603 1-216-827-11 METAL CHIP 3.3K 5% 1/10W R604 1-216-833-11 METAL CHIP 10K 5% 1/10W R605 1-216-841-11 METAL CHIP 47K 5% 1/10W R606 1-216-825-11 METAL CHIP 2.2K 5% 1/10W R607 1-216-833-11 METAL CHIP 10K 5% 1/10W R608 1-216-833-11 METAL CHIP 10K 5% 1/10W R609 1-216-825-11 METAL CHIP 2.2K 5% 1/10W R610 1-216-832-11 METAL CHIP 8.2K 5% 1/10W R611 1-216-837-11 METAL CHIP 22K 5% 1/10W R630 1-216-857-11 METAL CHIP 1M 5% 1/10W R631 1-216-837-11 METAL CHIP 22K 5% 1/10W R632 1-216-821-11 METAL CHIP 1K 5% 1/10W R633 1-216-833-11 METAL CHIP 10K 5% 1/10W R635 1-216-809-11 METAL CHIP 100 5% 1/10W R640 1-216-833-11 METAL CHIP 10K 5% 1/10W R641 1-218-867-11 METAL CHIP 6.8K 5% 1/10W R642 1-216-825-11 METAL CHIP 2.2K 5% 1/10W 0R644 1-219-787-17 FUSIBLE 5.6 5% 1/4W R645 1-216-836-11 METAL CHIP 18K 5% 1/10W R646 1-216-836-11 METAL CHIP 18K 5% 1/10W R647 1-216-837-11 METAL CHIP 22K 5% 1/10W R648 1-216-825-11 METAL CHIP 2.2K 5% 1/10W R651 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R652 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R653 1-216-827-11 METAL CHIP 3.3K 5% 1/10W R654 1-216-833-11 METAL CHIP 10K 5% 1/10W R655 1-216-841-11 METAL CHIP 47K 5% 1/10W R656 1-216-825-11 METAL CHIP 2.2K 5% 1/10W R657 1-216-833-11 METAL CHIP 10K 5% 1/10W R658 1-216-833-11 METAL CHIP 10K 5% 1/10W R659 1-216-825-11 METAL CHIP 2.2K 5% 1/10W R660 1-216-832-11 METAL CHIP 8.2K 5% 1/10W R661 1-216-837-11 METAL CHIP 22K 5% 1/10W R680 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R681 1-216-825-11 METAL CHIP 2.2K 5% 1/10W R682 1-216-825-11 METAL CHIP 2.2K 5% 1/10W R683 1-216-819-11 METAL CHIP 680 5% 1/10W R684 1-216-827-11 METAL CHIP 3.3K 5% 1/10W R685 1-216-827-11 METAL CHIP 3.3K 5% 1/10W R686 1-216-827-11 METAL CHIP 3.3K 5% 1/10W R687 1-216-841-11 METAL CHIP 47K 5% 1/10W R688 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R689 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R690 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R691 1-216-833-11 METAL CHIP 10K 5% 1/10W R692 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R693 1-216-841-11 METAL CHIP 47K 5% 1/10W R694 1-216-837-11 METAL CHIP 22K 5% 1/10W R695 1-216-833-11 METAL CHIP 10K 5% 1/10W < VARIABLE RESISTOR > RV603 1-241-768-11 RES, ADJ, CARBON 220K RV653 1-241-768-11 RES, ADJ, CARBON 220K < TRANSFORMER > T601 1-423-980-11 TRANSFORMER, BIAS OSCILLATION ************************************************************ 1-689-901-11 THR BOARD ********** < CONNECTOR > * CN992 1-564-704-11 PIN, CONNECTOR (SMALL TYPE) 2P < THERMISTOR(POSITIVE) > THP821 1-807-796-11 THERMISTOR ************************************************************ 1-689-608-11 VOL BOARD ********** < CAPACITOR > C852 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C853 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V < SWITCH > S851 1-478-127-11 ENCODER, ROTARY (VOLUME) ************************************************************ MISCELLANEOUS ************** 6 1-698-792-11 FAN, DC 8 1-693-626-11 TUNER (FM/AM) 9 1-773-009-11 WIRE (FLAT TYPE)(15 CORE) 73 1-796-351-51 MECHANISM, SIGNAL CASSETTE 75 1-773-114-11 WIRE (FLAT TYPE)(19 CORE) 83 1-773-038-11 WIRE (FLAT TYPE)(17 CORE) 84 1-824-335-11 WIRE (FLAT TYPE)(8 CORE) 0102 1-769-744-52 CORD, POWER 173 1-782-817-11 WIRE (FLAT TYPE)(16 CORE) 0601 A-4735-357-A BASE ASSY, OP (KSM-213D) 0F901 1-533-465-11 FUSE, GLASS TUBE (DIA. 5)(T1AL/250V) 0F904 1-533-468-11 FUSE, GLASS TUBE (DIA. 5)(T2AL/250V) M901 A-4735-337-A MOTOR (LD) ASSY (LOADING) 0T901 1-443-037-11 POWER TRANSFORMER THR The components identified by mark 0 or dotted line with mark 0 are critical for safety. Replace only with part number specified. VOL TC Ver 1.1 2003.11 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 61 HCD-GP7 Ref. No. Part No. Description Remarks MEMO www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com HCD-GP7 REVISION HISTORY Clicking the version allows you to jump to the revised page. Also, clicking the version at the upper right on the revised page allows you to jump to the next revised page. Ver. Date Description of Revision 1.0 2003.06 New 1.1 2003.11 Deletion of 3-13. KSS-213D in DISASSEMBLY. Addition of Description for Ref. No. F901 and F904. Change of Part No. for Ref. No. 601 (KSM-213D) (SPM-03061) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com
