1 Ver. 1.1 2005. 12 Model Name Using Similar Mechanism HCD-GNZ7D/GNZ8D/GNZ9D DVD DVD Mechanism Type CDM74HF-DVBU101//C Section Optical Pick-up Name KHM-310CAB/C2NP Tape Deck Model Name Using Similar Machanism HCD-GNZ7D/GNZ8D/GNZ9D Section Tape Transport Mechanism Type CWM43FR601 SERVICE MANUAL E Model Amplifier section The following measured at AC 120, 220, 230 – 240 V, 50/60 Hz Continuous RMS power output (reference) 50 + 50 watts (6 ohms at 1 kHz, 10% THD) Inputs MIC (phone jack): sensitivity 1 mV, impedance 10 kilohms Outputs VIDEO OUT (phono jack): max. output level 1 Vp-p, unbalanced, Sync negative, load impedance 75 ohms DIGITAL OPTICAL OUT (Square optical connector jack, rear panel) Wavelength 660 nm PHONES (stereo mini jack): accepts headphones of 8 ohms or more FRONT SPEAKER: Use only the supplied speaker SS-GNZ5D SPECIFICATIONS Disc player section System Compact disc and digital audio and video system Laser Semiconductor laser (DVD: λ=650 nm, CD: λ=790 nm) Emission duration: continuous Frequency response DVD (PCM 48 kHz): 2 Hz – 22 kHz (±1 dB) CD: 2 Hz – 20 kHz (±1 dB) Video color system format NTSC, PAL Tape deck section Recording system 4-track 2-channel stereo Frequency response 40 – 13,000 Hz (±3 dB), using Sony TYPE I cassette Sony Corporation Home Audio Division Published by Sony Engineering Corporation 9-879-821-02 2005L04-1 © 2005. 12 – Continued on next page – DVD DECK RECEIVER • HCD-GNZ5D is the tuner, deck, DVD and amplifier section in MHC-GNZ5D. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 2 HCD-GNZ5D SAFETY-RELATED COMPONENT WARNING!! COMPONENTS IDENTIFIED BY MARK 0 OR DOTTED LINE WITH MARK 0 ON THE SCHEMATIC DIAGRAMS AND IN THE PARTS LIST ARE CRITICAL TO SAFE OPERATION. REPLACE THESE COMPONENTS WITH SONY PARTS WHOSE PART NUMBERS APPEAR AS SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUBLISHED BY SONY. Tuner section FM stereo, FM/AM superheterodyne tuner FM tuner section Tuning range 87.5 – 108.0 MHz (50-kHz step) Antenna FM lead antenna Antenna terminals 75 ohm unbalanced Intermediate frequency 10.7 MHz AM tuner section Tuning range 530 – 1,710 kHz (with the interval set at 10 kHz) 531 – 1,602 kHz (with the interval set at 9 kHz) Antenna AM loop antenna Antenna terminals External antenna terminal Intermediate frequency 450 kHz General Power requirements Indian model: 220 – 240 V AC, 50/60 Hz Thai model: 220 V AC, 50/60 Hz Other models: 120 V, 220 V or 230 – 240 V AC, 50/60 Hz Adjustable with voltage selector Power consumption 110 watts Dimensions (w/h/d) (excl. speakers) Approx. 280 × 326 × 365 mm Mass (excl. speakers) Approx. 9 kg Design and specifications are subject to change without notice. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 3 CAUTION Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure. HCD-GNZ5D NOTES ON HANDLING THE OPTICAL PICK-UP BLOCK OR BASE UNIT The laser diode in the optical pick-up block may suffer electrostatic breakdown because of the potential difference generated by the charged electrostatic load, etc. on clothing and the human body. During repair, pay attention to electrostatic break-down and also use the procedure in the printed matter which is included in the repair parts. The flexible board is easily damaged and should be handled with care. Notes on Chip Component Replacement • Never reuse a disconnected chip component. • Notice that the minus side of a tantalum capacitor may be damaged by heat. Flexible Circuit Board Repairing • Keep the temperature of soldering iron around 270°C during re- pairing. • Do not touch the soldering iron on the same conductor of the circuit board (within 3 times). • Be careful not to apply force on the conductor when soldering or unsoldering. UNLEADED SOLDER Boards requiring use of unleaded solder are printed with the lead free mark (LF) indicating the solder contains no lead. (Caution: Some printed circuit boards may not come printed with the lead free mark due to their particular size) : LEAD FREE MARK Unleaded solder has the following characteristics. • Unleaded solder melts at a temperature about 40 °C higher than ordinary solder. Ordinary soldering irons can be used but the iron tip has to be applied to the solder joint for a slightly longer time. Soldering irons using a temperature regulator should be set to about 350 °C. Caution: The printed pattern (copper foil) may peel away if the heated tip is applied for too long, so be careful! • Strong viscosity Unleaded solder is more viscou-s (sticky, less prone to flow) than ordinary solder so use caution not to let solder bridges occur such as on IC pins, etc. • Usable with ordinary solder It is best to use only unleaded solder but unleaded solder may also be added to ordinary solder. This appliance is claassified as a CLASS 1 LASER product. This label is located on the rear exterior. NOTES ON LASER DIODE EMISSION CHECK The laser beam on this model is concentrated so as to be focused on the disc reflective surface by the objective lens in the optical pick- up block. Therefore, when checking the laser diode emission, observe from more than 30 cm away from the objective lens. Laser component in this product is capable of emitting radiation exceeding the limit for Class 1. Ver. 1.1 Note on DMB11 board replacement New part of EEP ROM (IC103) on the DMB11 board cannot be used. Therefore, if the mounted DMB11 board (A-1109-317-A, etc.) is replaced, exchange new EEP ROM (IC103) with that used before the replacement. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 4 HCD-GNZ5D MODEL IDENTIFICATION – BACK PANEL – MODEL PARTS No. GNZ5D: PH 2-582-753-0s GNZ5D: E3, E15 2-582-753-1s GNZ5D: E12, E13 2-582-753-2s PARTS No. • Abbreviation E3 : 240 V AC area in E model E12 : 220 – 240 V AC area in E model E13 : 220 – 230 V AC area in E model E15 : Iran model PH : Philippine model www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 5 TABLE OF CONTENTS HCD-GNZ5D 7. DIAGRAMS 7-1. Circuit Boards Location .................................................... 26 7-2. Block Diagram — RF/Servo Section — ........................... 27 7-3. Block Diagram — Video Section — ................................. 28 7-4. Block Diagram — Main Section — .................................. 29 7-5. Block Diagram — Function/Power Section — ................. 30 7-6. Printed Wiring Boards — Driver Section —..................... 32 7-7. Schematic Diagram — Driver Section — ......................... 33 7-8. Printed Wiring Board — DMB11 Section — ................... 34 7-9. Schematic Diagram — DMB11 Section (1/4) — ............. 36 7-10. Schematic Diagram — DMB11 Section (2/4) — ............. 37 7-11. Schematic Diagram — DMB11 Section (3/4) — ............. 38 7-12. Schematic Diagram — DMB11 Section (4/4) — ............. 39 7-13. Printed Wiring Boards — Audio Section — ..................... 40 7-14. Schematic Diagram — Audio Section (1/3) —................. 41 7-15. Schematic Diagram — Audio Section (2/3) —................. 42 7-16. Schematic Diagram — Audio Section (3/3) —................. 43 7-17. Printed Wiring Board — Video Section — ....................... 44 7-18. Schematic Diagram — Video Section — .......................... 45 7-19. Printed Wiring Board — Front AMP Section — .............. 46 7-20. Schematic Diagram — Front AMP Section — ................. 47 7-21. Schematic Diagram — Panel Section (1/2) — ................. 48 7-22. Schematic Diagram — Panel Section (2/2) — ................. 49 7-23. Printed Wiring Boards — Panel Section — ...................... 50 7-24. Printed Wiring Board — Jack Section — ......................... 51 7-25. Schematic Diagram — Jack Section — ............................ 52 7-26. Schematic Diagram — Power Section — ......................... 53 7-27. Printed Wiring Board — Trans Section — ....................... 54 7-28. Printed Wiring Board — Sub Trans Section — ................ 55 8. EXPLODED VIEWS 8-1. Main Section ..................................................................... 64 8-2. Front Panel Section (1)...................................................... 65 8-3. Front Panel Section (2)...................................................... 66 8-4. Front Panel Section (3)...................................................... 67 8-5. DVD Block Section ........................................................... 68 8-6. Chassis Section ................................................................. 69 8-7. Audio Board Section ......................................................... 70 8-8. DVD Mechanism Deck Section (1) .................................. 71 8-9. DVD Mechanism Deck Section (2) .................................. 72 9. ELECTRICAL PARTS LIST ........................................ 73 1. SERVICE NOTE 1-1. Service Position of CDM .................................................... 6 1-2. Service Position of DMB11 Board, Video Board ............... 6 1-3. Service Position of TCM ..................................................... 7 1-4. Service Position of Front AMP Board ................................ 7 2. GENERAL Main Unit ................................................................................ 8 Remote Control ....................................................................... 9 3. DISASSEMBLY 3-1. Case ................................................................................... 11 3-2. Loading Panel Assy ........................................................... 11 3-3. Front Panel Section ........................................................... 12 3-4. DVD Block Section ........................................................... 12 3-5. Tape Mechanism Deck Section ......................................... 13 3-6. Panel Board ....................................................................... 13 3-7. Jack Board ......................................................................... 14 3-8. Back Panel Section ............................................................ 14 3-9. Boards Section .................................................................. 15 3-10. Audio Board ...................................................................... 15 3-11. DVD Mechanism Block, Video Board, DMB11 Board .... 16 3-12. Pick-up Unit ...................................................................... 16 3-13. SW Board, Driver Board ................................................... 17 3-14. Sensor Board ..................................................................... 17 3-15. Motor (TB) Board ............................................................. 18 3-16. Motor (LD) Board ............................................................. 18 4. TEST MODE 4-1. General Description .......................................................... 20 4-2. Starting Test Mode ............................................................ 20 4-3. Drive Manual Operation.................................................... 20 4-4. Mirror Time Adjustment ................................................... 20 4-5. Executing IOP Measurement ............................................ 22 5. MECHANICAL ADJUSTMENTS ............................... 23 6. ELECTRICAL ADJUSTMENTS................................. 24 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 6 HCD-GNZ5D 1-2. SERVICE POSITION OF DMB11 BOARD, VIDEO BOARD 1-1. SERVICE POSITION OF CDM SECTION 1 SERVICE NOTE stand DVD mechanism block PANEL board DMB11 board VIDEO board J-2501-102-A www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 7 HCD-GNZ5D 1-4. SERVICE POSITION OF FRONT AMP BOARD 1-3. SERVICE POSITION OF TCM earth is taken FRONT AMP board insulating plate AUDIO board earth is taken www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 8 HCD-GNZ5D SECTION 2 GENERAL This section is extracted from instruction manual. Additional Information 67GB Main unit CD SYNC wg (38) Deck A ws (37, 39) Deck B qg (37, 38, 39, 46) DIRECTION qd (37, 38, 39) DISC 1 – 3 qs (12, 14, 38, 56) DISC SKIP/EX-CHANGE qa (9, 11, 12, 14, 38) Disc tray 9 (11) DISPLAY 2 (47, 48, 56) Display window 6 DVD wk (9, 38) EQ BAND/MEMORY 4 (41) GROOVE wh (40) MIC jack ql (41) MIC LEVEL qk (41) Operation Dial (l L) 5 (41) PHONES jack w; PRESET EQ wj (40, 41) REC PAUSE/START wf (38, 39) Remote sensor 3 SOUND FIELD 7 (40) TAPE A/B wk (37, 38, 39) TUNER/BAND wk (35, 36, 39) TUNING + qh (35, 36) TUNING – wa (35, 36) VOLUME control qj (42) ?/1 (power) 1 (8, 36, 45, 56) nN (play) 8 (11, 29, 37, 38) X (pause) 8 (8, 11, 37) x (stop) 8 (9, 11, 30, 37, 38, 56) Z OPEN/CLOSE q; (11) Z PUSH (deck B) (eject) qf (37) M (fast forward) qh (12, 37) y (slow forward) qh (12) m (rewind) wa (12, 37) (slow rewind) wa (12) Z PUSH (deck A) (eject) wd (37) List of button locations and reference pages How to use this page Use this page to find the location of buttons and other parts of the system that are mentioned in the text. Illustration number r TAPE A/B wk (37, 38, 39) R R Name of button/part Reference page ALPHABETICAL ORDER A — N O — Z BUTTON DESCRIPTIONS M y M y nN X x qd qs qf qg q; qa 1 2 9 8 7 6 5 3 4 qh qj qlqk w; wa wk wj wh wd wf wg ws continued www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 9 HCD-GNZ5D Remote control ALBUM +/– wf (11, 50) ANGLE 5 (34) AUDIO 4 (25, 41) CLEAR es (10, 14, 15, 16, 20, 23) DISC SKIP w; (12, 14) DISPLAY qj (47, 48) ENTER qs (9, 13, 14, 16, 17, 19, 21, 23, 27, 35, 43, 45, 46, 56) FM MODE ws (36) FUNCTION +/– 2 (10, 11, 35, 36) KARAOKE MODE qg (41) KARAOKE PON qh (42) MENU 6 (16, 18, 19, 21, 35) Number buttons* qf (17, 31) PICTURE NAVI 3 (20, 24) PRESET + wh (36) PRESET – e; (36) REPEAT ws (15) SLEEP qk (45) SOUND FIELD wa (40) SUBTITLE wd (34) THEATRE SYNC ql (50) TIMER MENU eg (9, 45, 46) TIME/TEXT ef (47, 48) TOP MENU qd (16) TUNING + 9 (35, 36) TUNING – qa (35, 36) TV wk (50) TV CH + wh (50) TV CH – e; (50) TV/VIDEO qk (50) TV VOL +/–* 7 (50) VOLUME +/–* 7 (45) ?/1 (power) 1 (8, 45, 56) TV ?/1 1 (50) REPLAY/ADVANCE / c STEP/STEP C 8 (12) SLOW y 9 (12) M (fast forward) 9 (12, 37) X (pause) q; (11, 37) SLOW qa (12) m (rewind) qa (12, 37) M/m/ (go forward) wh (11) x (stop) wj (37) . (go back) e; (11) H (play)* wl (11, 29) O RETURN ea (17) -/-- es KEY CONTROL #/2 ed (42) * The H, number 5 and VOLUME + (TV VOL +) buttons have tactile dots. Use the tactile dots as references when operatihng the system. ALPHABETICAL ORDER A — Q R — Z BUTTON DESCRIPTIONS b B < z V v + – + – + + – + X y y x m M . > O b B < z < z V v + – + – + X x m M . > O # 2 c C < z H y y H c C – 2 # 1 2 3 4 5 6 7 8 9 q; qa qs qd qf qg qh qj qk ql w; wa ws wd wf wg wh wj wk wl e; ea es ed ef eg www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 10 HCD-GNZ5D SECTION 3 DISASSEMBLY Note : Disassemble the unit in the order as shown below. 3-15. MOTOR (TB) BOARD (Page 18) 3-16. MOTOR (LD) BOARD (Page 18) 3-1. CASE (Page 11) 3-2. LOADING PANEL ASSY (Page 11) SET 3-3. FRONT PANEL SECTION (Page 12) 3-12. PICK-UP UNIT (Page 16) 3-14. SENSOR BOARD (Page 17) 3-13. SW BOARD, DRIVER BOARD (Page 17) 3-4. DVD BLOCK SECTION (Page 12) 3-8. BACK PANEL SECTION (Page 14) 3-9. BOARDS SECTION (Page 15) 3-10. AUDIO BOARD (Page 15) 3-11. DVD MECHANISM BLOCK, VIDEO BOARD, DMB11 BOARD (Page 16) 3-6. PANEL BOARD (Page 13) 3-5. TAPE MECHANISM DECK SECTION (Page 13) 3-7. JACK BOARD (Page 14) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 11 HCD-GNZ5D 3-2. LOADING PANEL ASSY Note : Follow the disassembly procedure in the numerical order given. 3-1. CASE 2 screw (case 3 TP2) 7 screw (case 3 TP2) 1 screw (case 3 TP2) 6 screw (case 3 TP2) 5 case (side-R) 0 case (side-R) qg case (top) 3 screw (+BVTT 3 × 6) qa two screws (+BVTT 3 × 6) qs two screws (+BVTP 3 × 10) 8 screw (+BVTT 3 × 6) 4 9 qd qf qd 3 Pull-out the disc tray. 5 loading panel assy 2 Turn the pulley to the direction of arrow. 1 The DVD mechanism block has a cover. So the pulley may not be rotated unless the cover is opened. pulley Front panel side CD mechanism deck (CDM74HF) cover (B-CDM) 4 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 12 HCD-GNZ5D 3-3. FRONT PANEL SECTION qs CN601 (3P) qa CN602 (8P) 0 CN751 (10P) 7 CN752 (27 core) 1 CN005 (13 core) 8 CN755 (4P) 9 CN203 (4P) 2 CN102 (13 core) 3 screw (+BVTP 3 × 10) 4 screw (+BVTP 3 × 10) 6 5 four screws (+BVTT 3 × 6) qd front panel section 3-4. DVD BLOCK SECTION 1 screw (+BVTP 3 × 10) 2 three screws (+BVTT 3 × 6) 3 4 CN301 (17 core) 5 CN851 (8P) 6 DVD block section www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 13 HCD-GNZ5D 3-6. PANEL BOARD 3-5. TAPE MECHANISM DECK SECTION 4 two screws (+BVTP 2.6 (3CR)) 5 two screws (+BVTP 2.6 (3CR)) 2 screw (+BVTP 2.6 (3CR)) 3 GUARD board 6 screw (+BVTP 2.6 (3CR)) 7 tape mechanism deck clamp lug lug 1 connector 5 CN151 (7P) 6 PANEL board 4 six claws 1 five screws (+BVTP 2.6 (3CR)) 2 two screws (+BVTP 2.6 (3CR)) 3 three screws (+BVTP 2.6 (3CR)) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 14 HCD-GNZ5D 3-7. JACK BOARD 4 bracket (TC-JACK) 5 JACK board 1 mic knob 2 two screws (+BVTP 2.6 (3CR)) 3 two screws (+BVTT 3 × 6) 3-8. BACK PANEL SECTION 8 back panel section 5 three screws (+BVTT 3 × 6) 3 two screws (+BVTT 3 × 6) 4 screw (+BVTP 3 × 10) 7 CN754 (2P) 6 1 CN753 (9P) 2 CN306 (3P) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 15 HCD-GNZ5D 3-10. AUDIO BOARD 3-9. BOARDS SECTION 6 boards section 4 two screws (+BV sumitite (B3)) 5 two screws (+BV sumitite (B3)) 3 two screws (+BVTT 3 × 6) 2 CN914 (10P) 1 CN915 (4P) 2 AUDIO board CN201 CN202 1 claw www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 16 HCD-GNZ5D 3-12. PICK-UP UNIT 3-11. DVD MECHANISM BLOCK, VIDEO BOARD, DMB11 BOARD qf screw (+BVTP 3 × 8) qj bracket (DVD) qg screw (+BVTP 3 × 8) qh 3 two screws (+BVTT 3 × 6) 6 three screws (+BVTT 3 × 6) 0 two screws (+BVTT 3 × 6) qd two screws (+BVTP 3 × 8) qa two screws (+BVTT 3 × 6) 5 VIDEO board 7 REINFORCE (CDM) board qs DMB11 board 8 CN201 (6P) 9 CN101 (24 core) qk DVD mechanism block 2 CN401 (5P) 1 CN801 (5P) 4 claw 2 two insulator screws 4 two insulators 5 two insulators 3 two insulator screws 6 pick-up unit 7 holder (310) 1 floating screw (+PTPWH M2.6) Note : Be short-circuited of the land of optical pick-up when CN101 is done in pulling out. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 17 HCD-GNZ5D 3-13. SW BOARD, DRIVER BOARD 6 DRIVER board 2 SW board 3 CN704 4 CN703 7 CN702 (flat type) 5 two screws (+BTTP (M2.6)) 1 screw (+BTTP (M2.6)) 3-14. SENSOR BOARD 2 tray 3 belt (table) 5 pulley (table) 8 screw (+BTTP (M2.6)) 9 SENSOR board 7 gear (geneva) 0 CN731 1 floating screw (+PTPWH M2.6) 6 floating screw (+PTPWH M2.6) 4 floating screw (+PTPWH M2.6) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 18 HCD-GNZ5D 3-15. MOTOR (TB) BOARD 3-16. MOTOR (LD) BOARD 5 Remove the two solders of motor. 4 MOTOR (TB) board 2 stopper 2 stopper 6 table motor assy (M741) table assy 3 two screws (+BTTP (M2.6)) 1 4 Remove the two solders of motor. 3 MOTOR (LD) board 1 belt (loading) 5 loading motor assy (M751) 2 two screws (+BTTP (M2.6)) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 19 HCD-GNZ5D SECTION 4 TEST MODE [Cold Reset] • The cold reset clears all data including preset data stored in the RAM to initial conditions. Execute this mode when returning the set to the customer. Procedure: 1. Press three buttons of x , [DISPLAY] and [DISC 1] simultaneously. 2. The message “COLD RESET” is displayed, and the set is reset. [Tuner Step Change] • A step of AM channels can be changed over between 9 kHz and 10 kHz. Procedure: 1. Press the `/1 button to turn the power ON, and set the function to TUNER/BAND “AM”. 2. Press the `/1 button to turn the power OFF. 3. Press two buttons of [TUNING +] and `/1 simultaneously, and the message changes to “AM 9 k STEP” or “AM 10 k STEP”, and thus the channel step is changed over. [Color System Change] Procedure: 1. Press the `/1 button to turn the power ON. 2. Press two buttons of X and `/1 simultaneously. 3. The message “COLOR NTSC” or “COLOR PAL” is displayed. [Disc Tray Lock] The disc tray lock function for the antitheft of a demonstration disc in the store is equipped. Setting Procedure : 1. Press the ?/1 button to turn the power ON. 2. Press two buttons of x and Z simultaneously for five seconds. 3. The message “LOCKED” is displayed, and the tray is locked. Releasing Procedure : 1. Press two buttons of x and Z simultaneously for five seconds. 2. The message “UNLOCKED” is displayed, and the tray is unlocked. Note: When the message “LOCKED” is displayed, the tray lock is not released by turning power ON/OFF with the ?/1 button. [Panel Test Mode] • This mode is used to check the fluorescent indicator tube, LEDs, keyboard, volume and phones. Enter The Panel Test Mode Procedure: 1. Press three buttons of x , [DISPLAY] and [DISC 2] simulta- neously. 2. LEDs and fluorescent indicator tube are all turned on. Model Information Procedure: 1. It puts it into the start of the panel test mode. 2. Press the [DIRECTION] button, the mode change model name or destination display. Key Test Mode Procedure: 1. It puts it into the start of the panel test mode. 2. Press the Y button, the mode change key test mode. VACS Display Procedure: 1. It puts it into the start of the panel test mode. 2. Press the X button, the mode change VACS display. The message “VACS 0+0” is displayed. Version Display Procedure: 1. It puts it into the start of the panel test mode. 2. Press the [DIRECTION] button, the mode change version display. Press the [DISPLAY] button, the mode change version or days is displayed. 3. You can exit the Test Mode when you press three buttons of X , [DISPLAY] and [DISC 2] simultaneously. [Common Test Mode] • This mode is used to check operations of the respective sections of Amplifier and Tape. Procedure: • To enter MC Test Mode 1. Press the `/1 button to turn the power ON. 2. Press three buttons of x , [DISPLAY] and [DISC 3] simulta- neously. * Check of Amplifier Initial settings: EQ , FLAT VACS , ON • When you press the [EQ BAND/MEMORY] button, the message “GEQ FLAT” is displayed, and the entire band of the graphic equalizer is set to the center level. • Whenever you press the [GROOVE] button, it toggles between “VACS ON” and “VACS OFF” so that you can switch ON or OFF of VACS. * To return to normal mode again. 1. When you want to exit this mode, press the `/1 button. 2. The cold reset is enforced at the same time. [DVD and CD Ship Mode (No Memory Clear)] • This mode moves the position to the position durable to vibration. Use this mode when returning the set to the customer after repair. Procedure: 1. Press the `/1 button to turn the power ON. 2. Press two buttons of x and [DISC SKIP] simultaneously. 3. After the “STANDBY” display blinks 15 times, the message “LOCK” is displayed, and the DVD ship mode is set. [DVD and CD Ship Mode (Memory Clear)] • This mode moves the pickup to the position durable to vibration. Use this mode when returning the set to the customer after repair. Procedure: 1. Press the `/1 button to turn the power ON. 2. Press three buttons of x , [DISPLAY] and [DIRECTION] simul- taneously. 3. After the “STANDBY” display blinks 15 times, the message “LOCK” is displayed, and the DVD ship mode is set. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 20 HCD-GNZ5D DVD SECTION 4-4. MIRROR TIME ADJUSTMENT To enter Mirror Time Adjustment, press 5 “R” button on the remote commander. The screen will appear as below. There are five main commands in the Mirr time Adjust menu as shown in the figure above. The functions of each command are described in the following page. 1. CD MIRR time Check This command checks the Mirror time value for CD disc. 2. DVD MIRR time Check This command checks the Mirror time value for DVD disc. 3. Threshold This command displays the threshold value between CD and DVD mirror time. 4. Save to EEPROM This command saves an adjusted mirror time value to the EEPROM. 5. Default set MIRR time This command will set CD and DVD mirror time to firmware default value. [Open] / [Close] Pressing the A button controls the tray for disc change during mirror time adjustment. [0] Return to previous menu Press 0 “R” button to return to previous menu. 4-4-1. EXECUTING MIRROR TIME ADJUSTMENT In order to execute mirror time adjustment, the following standard procedures must be followed. (1) In standby mode, press three buttons x , A and [VOLUME +] simultaneously. (2) Select “2. Drive Manual Operation”. MIRR time Adjust Menu 1. CD MIRR time Check: 2. DVD MIRR time Check: 3. Threshold: 4. Save to EEPROM 5. Default set MIRR time [Open] Tray open [Close] Tray close [0] Return to previous menu Remocon Diagnosis Menu 0. External Chip Check 1. Servo Parameter Check 2. Drive Manual Operation 3. Emergency History Check 4. Version information 5. Video Level Adjustment Model : GVLXD_xx IF-con : Ver. xx.xx (xxxx) Syscon : Ver. x.xxx Ver. 1.1 [TEST DISC LIST] Be sure to use the DVD disc that matches the signal standards of your region. • CD YEDS-18 (Part No.: 3-702-101-01) PATD-012 (Part No.: 4-225-203-01) • DVD SL (Single Layer) NTSC : HLX-503 (Part No.: J-6090-069-A) HLX-504 (Part No.: J-6090-088-A) PAL : HLX-506 (Part No.: J-6090-077-A) • DVD DL (Dual Layer) NTSC : HLX-501 (Part No.: J-6090-071-A) HLX-505 (Part No.: J-6090-089-A) PAL : HLX-507 (Part No.: J-6090-078-A) 4-1. GENERAL DESCRIPTION The Mirror Time and IOP measurement allows you to make diagnosis and adjustment simply by using the remote commander and monitor TV. The instructions, diagnosis results, etc. are given on the on screen display (OSD). The Mirror Time and IOP measurement is required is such events where servicing a DVD-Player includes changing the Base Unit (BU). For each new BU to be used with a certain MV-044 board, Mirror Time and IOP measurement need to be carried out. 4-2. STARTING TEST MODE Press three buttons x , A and [VOLUME +] simultaneously with the DVD player in standby mode. The Test Mode starts, then the menu shown below will be displayed on the TV screen. The menu above is the Remocon Diagnosis Menu screen which consists of six main function. At the bottom of the menu screen, the model name and IF-con version. To enter Mirror Time Adjustment menu, press button 2 “R” on the remote commander to enter Drive Manual Operation menu. To exit from the Test Mode, press the power button on the remote commander. 4-3. DRIVE MANUAL OPERATION The Drive Manual Operation menu consists of five main function. By pressing 2 “R” button on the remote commander in the Remocon Diagnosis Menu, the screen will appear as below. Remocon Diagnosis Menu 0. External Chip Check 1. Servo Parameter Check 2. Drive Manual Operation 3. Emergency History 4. Version Information 5. Video Level Adjustment Model Name : GVLXD_XX IF-con : V Syscon : Ver. er. xx.xx (xxxx) x.xxx Drive Manual Operation 1. Servo Control 2. Track/Layer Jump 3. Manual Adjustment 4. Tray Aging Mode 5. MIRR time Adjust 0. Return to Top Menu www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 21 HCD-GNZ5D (3) Select “5. MIRR time Adjust”. (4) Select “5. Default set MIRR time”. (5) Select “3. Threshold”. (6) Confirm the number. If it is 7D, go to next step. If it is any other value, return to step 4. (7) Push A button to eject tray. (8) Insert Test Disc HLX-504 into tray. (9) Push A button to close tray. (10) Push “2. DVD MIRR time Check”. (11) Wait for HEX number to display. (12) Confirm the number, if XX is 28 ~ 70, proceed with next step. If no, return to 8. (13) Push “4. Save to EEPROM”. Drive Manual Operation 1. Servo Control 2. Track/Layer Jump 3. Manual Adjustment 4. Mecha test mode 5. MIRR time Adjust 0. Return to Top Menu MIRR time Adjust Menu 1. CD MIRR time Check: 2. DVD MIRR time Check: 3. Threshold: 4. Save to EEPROM: 5. Default set MIRR time: [Open] Tray open [Close] Tray close [0] Return to previous menu MIRR time Adjust Menu 1. CD MIRR time Check: 2. DVD MIRR time Check: 3. Threshold: 7D 4. Save to EEPROM: 5. Default set MIRR time: [Open] Tray open [Close] Tray close [0] Return to previous menu MIRR time Adjust Menu 1. CD MIRR time Check: 2. DVD MIRR time Check: xx xx 3. Thereshold: 4. Save to EEPROM: 5. Default set MIRR time: [Open] tray open [close] Tray close [0] Return to previous menu (14) Confirm the same values are displayed. If it is not same, return to step 7. (15) Push A button to eject tray. (16) Take out HLX-504 and insert Test Disc YEDS-18 into tray. (17) Push A button to close tray. (18) Push “1. CD MIRR time check”. (19) Wait for HEX number to display. (20) Confirm the number, if YY is 5A ~ E8, proceed with next step. If no, return to 15. (21) Push “4. Save to EEPROM”. (22) Confirm the same values are displayed. If it is not the same, return to step 15. (23) Push A button to eject tray. (24) Remove Test Disc YEDS-18 from tray. (25) Push A button to close tray. (26) Press 0 “R” button to the Drive Manual Operation menu. (27) Press 0 “R” button to return to the Remocon Diagnosis Menu. (28) Press the ?/1 button to switch OFF set. MIRR time Adjust Menu 1. CD MIRR time Check: 2. DVD MIRR time Check: XX XX 3. Threshold: 4. Save to EEPROM: 5. Default set MIRR time: [Open] Tray open [close] Tray close [0] Return to previous menu MIRR time Adjust Menu 1. CD MIRR time Check: yy YY 2. DVD MIRR time Check: XX XX 3. Threshold: 4. Save to EEPROM: 5. Default set MIRR time: [Open] Tray open [close] Tray close [0] Return to previous menu MIRR time Adjust Menu 1. CD MIRR time check: YY YY 2. DVD MIRR time check: XX XX 3. Threshold: 4. Save to EEPROM: 5. Default set MIRR time: [Open] Tray open [close] Tray close [0] Return to previous menu www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 22 HCD-GNZ5D 4-5. EXECUTING IOP MEASUREMENT In order to execute mirror time adjustment, the following standard procedures must be followed. (1) In standby mode, press three buttons x , A and [VOLUME +] simultaneously. (2) Select “2. Drive Manual Operation” by pressing the 2 “R” button on the remote commander. The screen will appear as below. (3) Select “3. Manual Adjustment” by pressing the 3 “R” button on the remote commander. The screen will appear as below. (4) Select Iop by pressing 6 “R” button on the remote commander. Remocon Diagnosis Menu 0. External Chip Check 1. Servo Parameter Check 2. Drive Manual Operation 3. Emergency History Check 4. Version information 5. Video Level Adjustment Model : GVLXD XX IF-con Ver : XX.XX (XXXX) Syscon Ver : X.XX Drive Manual Operation 1. Servo Control 2. Track/Layer Jump 3. Manual Adjustment 4. Tray Aging Mode 5. MIRR time adjust 0. Return to top Menu Manual Adjust 1. Track Balance Adjust: 2. Track Gain Adjust: 3. Focus Balance Adjust: 4. Focus Gain Adjust: 5. Eg boost Adjust: 6. Iop: 7. TRV. Level: 8. S curve(FE) Level: 9. RFL(PI) Level: 0. MIRR Time: o O Change Value [RETURN] Return to previous menu (5) Wait until a hexadecimal number appear. (6) Convert each data from hexadecimal to decimal using conversion table. (7) Substract between these two values. (8) If the remainder is smaller than 93 (decimal), then it is OK. However if the value is higher than 93, then the BU is defective and need to be change. (9) Press RETURN “R” button to return back to previous menu. (10) Press 0 “R” button to return to Top Menu and power OFF the DVD Player. Manual Adjust 1. Track Balance Adjust: 2. Track Gain Adjust: 3. Focus Balance Adjust: 4. Focus Gain Adjust: 5. Eq Boost Adjust: 6. Iop. 5B: 7. TRV. Level: 8. S curve(FE) Level: 9. RFL(PI) Level: 0. MIRR Time: Change Value [0] Return to previous menu www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 23 HCD-GNZ5D SECTION 5 MECHANICAL ADJUSTMENTS Precaution 1. Clean the following parts with a denatured alcohol-moistened swab: record/playback heads pinch rollers erase head rubber belts capstan idlers 2. Demagnetize the record/playback head with a head demagnetizer. 3. Do not use a magnetized screwdriver for the adjustments. 4. After the adjustments, apply suitable locking compound to the parts adjusted. 5. The adjustments should be performed with the rated power supply voltage unless otherwise noted. Torque Measurement 3.06 N • m to 6.96 N • m 31 to 71 g • cm (0.43 – 0.98 oz • inch) 0.19 N • m to 0.58 N • m 2 to 6 g • cm (0.02 – 0.08 oz • inch) 3.06 N • m to 6.96 N • m 31 to 71 g • cm (0.43 – 0.98 oz • inch) 0.19 N • m to 0.58 N • m 2 to 6 g • cm (0.02 – 0.08 oz • inch) 6.96 N • m to 14.02 N • m 71 to 143 g • cm (0.98 – 1.99 oz • inch) 9.80 N • m 100 g or more (3.53 oz or more) 9.80 N • m 100 g or more (3.53 oz or more) Mode Torque meter CQ-102C CQ-102C CQ-102RC CQ-102RC CQ-201B CQ-403A CQ-403R Meter reading FWD FWD back tension REV REV back tension FF/REW FWD tension REV tension www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 24 HCD-GNZ5D SECTION 6 ELECTRICAL ADJUSTMENTS VIDEO SECTION Video Level Check (VIDEO BOARD) Purpose This adjustment is made to satisfy the NTSC standard, and if not adjusted correctly, the brightness will be too large or small. Procedure: 1. Connect oscilloscope to VIDEO output. 2. Load a DVD reference disc playback. 3. Check the video signal level is 1.00±0.07Vp-p. DVD SECTION When the base unit is replaced, perform the adjustment and the measurement as shown below in this order. 1) MIRROR TIME ADJUSTMENT (See page 20) 2) EXECUTING IOP MEASUREMENT (See page 22) [TEST DISC LIST] Be sure to use the DVD disc that matches the signal standards of your region. • CD YEDS-18 (Part No.: 3-702-101-01) PATD-012 (Part No.: 4-225-203-01) • DVD SL (Single Layer) NTSC : HLX-503 (Part No.: J-6090-069-A) HLX-504 (Part No.: J-6090-088-A) PAL : HLX-506 (Part No.: J-6090-077-A) • DVD DL (Dual Layer) NTSC : HLX-501 (Part No.: J-6090-071-A) HLX-505 (Part No.: J-6090-089-A) PAL : HLX-507 (Part No.: J-6090-078-A) [RFMON Level Check] Connection: Procedure: 1. Connect an oscilloscope to CN105 pin 6 (RFMON) and CN105 pin 3 (GND) on the DMB11 board. 2. Turn the power on. 3. Set the test disc (refer to the TEST DISC LIST) on the tray and press H button to playback. 4. Confirm that oscilloscope waveform is clear and check RFMON signal level is correct or not. Note: A clear RFMON signal waveform means that the shape “◊” can be clearly distinguished at the center of the waveform. + – CN105 pin 6 (RFMON) CN105 pin 3 (GND) oscilloscope DMB11 board VOLT/DIV: 200 mV TIME/DIV: 500 ns RFMON signal waveform level: 0.58 ± 1.23 Vp-p (DVD) 0.57 ± 1.1 Vp-p (CD) oscilloscope set J801 VIDEO OUTPUT 75 Ω 1.00 ± 0.07 Vp-p (WHITE 100%) Ver. 1.1 Checking Location: DMB10 board (Side A) IC102 IC101 IC104 IC201 CN105 CN106 CN105 pin 3 (GND) CN105 pin 6 (RFMON) 1 6 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 25 HCD-GNZ5D 0 dB=0.775 V DECK SECTION 1. Demagnetize the record/playback head with a head demagnetizer. 2. Do not use a magnetized screwdriver for the adjustments. 3. After the adjustments, apply suitable locking compound to the parts adjust. 4. The adjustments should be performed with the rated power supply voltage unless otherwise noted. 5. The adjustments should be performed in the order given in this service manual. (As a general rule, playback circuit adjustment should be completed before performing recording circuit adjustment.) 6. The adjustments should be performed for both L-CH and R- CH. 7. Switches and controls should be set as follows unless otherwise specified. • Test Tape Record/Playback Head Azimuth Adjustment Note: Perform this adjustments for both decks Procedure: 1. Mode: Playback Tape Signal Used for P-4-A063 6.3 kHz, –10 dB Azimuth Adjustment DECK A DECK B 2. Turn the adjustment screw and check output peaks. If the peaks do not match for L-CH and R-CH, turn the adjustment screw so that outputs match within 1dB of peak. 3. Mode: Playback 4. After the adjustments, apply suitable locking compound to the pats adjusted. Adjustment Location: Playback Head (Deck A). Record/Playback/Erase Head (Deck B). set AUDIO board IC201 Pin 28 (L-CH) Pin 37 (R-CH) AUDIO board IC201 Pin 38 (GND) + – level meter test tape P-4-A063 (6.3 kHz, –10 dB) screw position L-CH peak within 1dB output level L-CH peak R-CH peak within 1dB screw position R-CH peak AUDIO board IC201 test tape P-4-A063 (6.3 kHz, –10 dB) pin 37 oscilloscope L-CH R-CH V H waveform of oscilloscope in phase 45° 90° 135° 180° good wrong pin 38 pin 28 L R reverse forward Ver. 1.1 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 26 HCD-GNZ5D 7-1. CIRCUIT BOARDS LOCATION SECTION 7 DIAGRAMS SUB TRANS board JACK board PANEL board TRANS board STREAM board AUDIO board FRONT AMP board LEAD PIN board SIRCS board DRIVER board SW board DMB11 board MOTOR (LD) board MOTOR (TB) board SENSOR board VIDEO board OPTICAL board POWER SWITCHING www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 27 27 HCD-GNZ5D HCD-GNZ5D 7-2. BLOCK DIAGRAM — RF/SERVO SECTION — : CD PLAY : DVD PLAY : SACD PLAY • Signal Path DETECTOR 6 2 3 4 5 11 10 19 18 252 253 DVDRFIP DVDA DVDB DVDC DVDD TPI TNI MC MD C D LD01 MD12 LD02 MSW MD11 OSP OSN CD/DVD RF AMP, FOCUS/TRACKING ERROR AMP DVD SYSTEM PROCESSOR DIGITAL SERVO PROCESSOR IC102(1/2) OPTICAL PICK-UP BLOCK 2AXIS DEVICE FOCUS/ TRACKING COIL 23 20 LI M SW 176 22 50 21 36 48 43 37 1 Q102 (2/2) AUTOMATIC POWER CONTROL (FOR DVD) Q101, Q103 VOLUME CONTROL Q102 (1/2) AUTOMATIC POWER CONTROL (FOR CD) LASER DIODE (FOR CD) LASER DIODE (FOR DVD) FOCUS COIL DRIVE 42 41 BUFFER 35 3 34 4 TRACKING COIL DRIVE 32 38 42 37 41 30 47 SLED MOTOR DRIVE FOCUS/TRACKING COIL DRIVER, SPINDLE, SLED MOTOR DRIVER IC201 27 28 SPINDLE MOTOR DRIVE M SPINDLE 46 47 FMO FOO MIC DMO TRO V REFO SPFG 40 IOPMON FOO RF A B C D F E CD LD PD LIMIT WR650 VR780 MSW DVD LD FCS+ FCS– TRK+ VCC TRK– SP+ SP– SL+ SL– D C B A V1P4 V1P4 9 NB B 8 NA A 30 29 SLED MOTOR DRIVE MM BUFFER 19 20 22 21 40 45 SYSTEM CONTROL IC101(1/3) 99 IFCK MTK_CLK 29 100 XIFCS MTK_CS 30 110 PRST MTK_XRST 23 98 IFSDO MTK_IN 28 101 IFSDI 105 IFBSY KRMOD/HSYNC MREQ MTK BUSY 24 KARAOKE/ MTK-REQ 87 MTK_OUT 27 TRO FMO FOO DMO TRO 10 13 FMO DMO 211 MUTE123 210 MUTE 170 TSDM 207 114 MIC/VSYNC 205 A MAIN SECTION SLED (Page 29) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 28 28 HCD-GNZ5D HCD-GNZ5D 7-3. BLOCK DIAGRAM — VIDEO SECTION — DVD SYSTEM PROCESSOR IC102(2/2) 217 ASDAT0 ASDAT1 ASDAT2 ASDAT4 225 SDPIF EEPROM IC103 6 5 SCL SDA CE WE OE FLASH ROM IC101 125-123, 121, 120, 118, 117, 115, 135, 133-128, 126 146, 147, 149-151, 158-160, 162, 164-166 22-26, 29-35 HIGHA0-7 IOA0-7, IOA18-IOA20 A16, A17 AD0 – AD7 A1-A20 DATA & ADDRESS BUS DATA & ADDRESS BUS 81-84,86-88,91 53-61, 67-72, 74-76, 78, 89, 92, 93 HD0 – HD7 A0 – A21 HD0 – HD7 A0 26 45 CE WE 28 OE 11 A0 – A19 DQ15/A-1 77 IOCS IOWA 79 IOUE 66 DQ0 – DQ7 RCLK CE WE OE SDRAM IC104 38 DRCLK RD0 – RD15 RA0 – RA11 RA0 – RA11 RD0 – RD15 142 RCS 19 RCS 138 RWE 16 RWE 140 RAS 18 RAS 139 CAS 17 CAS MDQM0 15 DQM0 MDQM1 39 DQM1 CKE 37 DRCKE 102 SCL 103 SDA 143 BA0 20 BS0 BA1 21 BS1 29,31,33,35,38,40,42,44 25-16, 9-1, 48 145 156 113 137 157 2,4,5,7,8,10,11,13,42,44,45,47,48,50,51,53 218 D/A CONVERTER IC301 J801 VIDEO OUT IC3711 219 222 198 YUV3 220 XRST 215 ACLK 214 ABCK 213 ALRCK 14 SDTI1 4 IN VIDEO MUTE 2 OUT 3 SAG 1 PS VIDEO AMP IC801 15 SDTI2 16 SDTI3 13 SDTI4 8 PDN 10 MCLK 9 BICK 17 LRCK 19 SCL 20 SDA 38 DOWNMIX L 37 2 FRONT L 1 DIGITAL OPTICAL TRANSMITTER IC306 DIGITAL OUT OPTICAL LOUT4+ LOUT4– (DMIXL) LOUT1+ LOUT1– (FL) B MAIN SECTION C MAIN SECTION XTALI XTALO 229 228 X101 27MHz IC3771 • Signal Path : VIDEO : Y : COMPONENT VIDEO : AUDIO : DIGITAL (Page 29) (Page 29) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 29 29 HCD-GNZ5D HCD-GNZ5D 7-4. BLOCK DIAGRAM — MAIN SECTION — 17 REC(DECK B) PB(DECK A) PB(DECK B) TUNER DOWN MIX L MIC 76 RELAY SWITCH 3 4 75 L R FAN SWITCH BIAS OSC Q601 T601 B VIDEO SECTION R-CH H FUNCTION/ POWER SECTION A RF/SERVO SECTION C VIDEO SECTION 1 2 FRONT L 57 NEG POS IC701 M751 (LOADING) M741 (TABLE) LOADING MOTOR DRIVE M NEG POS IC712 TABLE MOTOR DRIVE M LOD TBL Q731 IC731 TABLE ADDRESS SENSOR RE701 DISC TRAY ADDRESS DETECT CLOSE OPEN S751 OPEN/CLOSE DETECT R-CH A+9V MIC 3 1 35 34 DATA CLOCK DATA CLOCK 88 VACS/ ILLUMI VACS2 8 CDM EJECT /PROTECT 95 AC DET AC4 6 VIDEO MUTE VIDEO MUTE 8 TA MUTE 9 HP MUTE 6 FUN ON/OFF 12 FUN CTRL 7 FRONT RELAY 86 BIAS PB B DM SUR1 INB1 PB A REC 28 LOUT 27 BBB1 25 53 BBA1 POWER AMP IC401 REC/PB AMP, SOUND CONTROLLER IC201 SYSEM CONTORL IC101 (2/3) 7 6 15 13 OVERLOAD DET Q401 5 TM901 LCH 6 DI 8 DO 4 +9V 3 RCH DBFB DET AC DET DBFB SWITCH Q212 R-CH PROTECT DET R-CH Q282,283 +VH RY481 FRONT SPEAKER TM401 Q272 Q271 Q402,403 MUTE Q701 IN ST-BY +RE -RE AC DET D763,Q721-723 D753 SWITCH Q281 MUTE Q703 MUTE CONTROL Q791-795, 797 Q481,482 R-CH R-CH OVERHEAT DET TH401,Q416,417 AC DET J1002 RV1001 MIC 1 MIC LEVEL MIC AMP IC1001 (1/2) MIC AMP IC1001 (2/2) 69 DIN 70 DOUT 71 CLK 68 CE ST 19 TUNED 97 CDM ENC0/1/2 100 CDM TBL-SENS R-CH Q602,603 Q627, Q628 A+9V ERASE HEAD REC/PB HEAD R-CH R-CH PB HEAD MUTE CONTROL Q629-631 MUTE CONTROL Q623,624 MUTE Q622 J1004 PHONES R-CH AC3 FAN901 FAN (DECK A) HP901 HRPE901 (DECK B) TAPE MECHANISM DECK BLOCK SHUT(B) 84 SHUT(A) 83 PLAY SW(A)&(B)/A-HALF 82 85 79 B-HALF/REC TRG(A) A SOL REC(REV) B PHOTO A PHOTO B MODE A MODE B HALF A HALF REC(FWD) TRG(B) B SOL 78 CAP M+ B SOL DRIVE Q101,102 CAP M DRIVE Q103,104 A SOL DRIVE Q105,106 7 CL 9 CE TUNED 1 DOUT DIN CLK CE TUNED IC203 3 4 59 AM ANTENNA FM 75Ω COAXIAL MUTE CONTROL Q729 HP SW MIC 21 PB/REC 19 20 17 18 24 CAPM SW SIGNAL IN/OUT CONTROL IC102 (1/2) MUTE CONTROL Q728 7 9 4 2 7 9 4 2 • Signal Path : TUNER : AUDIO : PB (DECK A) : PB (DECK B) : REC (DECK B) : VIDEO : COMPONENT VIDEO • R-CH is omitted due to same as L-CH. (Page 28) (Page 27) (Page 28) (Page 30) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 30 30 HCD-GNZ5D HCD-GNZ5D 7-5. BLOCK DIAGRAM — FUNCTION/POWER SECTION — AC IN RY901 T911 POWER TRANSFORMER DVDM +9V M +9V A +9V 75 CLK 76 DI1 STBY RELAY P1 I P21 73 LATCH 77 RST CLK DI1 LATCH RSTB 3 26 4 2 SYSTEM CONTROL IC101 (3/3) VCC CONT HP SW 72 44-51, 53-61, 63 65-67 D110 I/1 SIRCS 7 D117,118 RING ILLUMINATION FUNCTION KEY S11,12,14-20 REMOTE CONTROL RECEIVER 94 S31-33,34,35,38,101 93 S51-57 92 89 74 4 STANDBY LED 12 RESET LED+9V +VF 20 AC CUT 43 – 31 X102 32.768kHz 11 10 XCOUT XCIN 13 15 X101 16MHz XOUT XIN ILLUMI 1/4 WAKE UP0 KEY2 VOL(A)&(B) /SW IN KEY1 KEY0 +VH -VH D471 F914 F915 F910 +VF DVD +5V D +3.3V D +3.3V LED +9V DVD POWER 22 UNREG+20V UNREG+15V D751 F918 D761 F919 D911 D+3.3V EVER+4V -VP EVER+4V VCC+3.3V +3.3V REG IC105 +3.3V RF+3.3V REG IC107 DVD+3.3V REG IC851 DVD POWER CONTROL Q861,870 RF +3.3V DVD +3.3V DVD +5V DVD+5V REG IC861 DVDM+9V REG IC941 M+9V REG IC942 A+9V REG IC943 DVD POWER CONTROL Q771,772 POWER CONTROL Q108,109 DVD+5V REG IC771 ILLUMINATION CONTROL Q111 18 RESET SWITCH Q107 RESET IC103 D+4V REG IC945 B- SWITCH Q902 POWER SWITCHING D+4V D+4V EVER+4V +3.3V RF+1.8V REG IC106 RF +1.8V 5 SIGNAL IN/OUT CONTROL IC102 (2/2) FL101 FLUORESCENT INDICATOR TUBE RELAY DRIVE Q901 H MAIN SECTION ENCODER S102 MASTER VOLUME FUNCTION KEY FUNCTION KEY G1-13 D101 D102 E3,E15,PH MODEL E3,E15,PH MODEL E3,E15,PH MODEL E12,E13 AUS E12,E13 MODEL E12,E13 MODEL IC104 S901 VOLTAGE SELECTOR 230-240 230-240V 220V 120V 220 120 (Page 29) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 31 31 HCD-GNZ5D HCD-GNZ5D • NOTE FOR PRINTED WIRING BOARDS AND SCHEMATIC DIAGRAMS Note on Printed Wiring Board: • X : parts extracted from the component side. • Y : parts extracted from the conductor side. • : Pattern from the side which enables seeing. (The other layer’s patterns are not indicated.) Caution: Pattern face side: Parts on the pattern face side seen from (Conductor Side) the pattern face are indicated. Parts face side: Parts on the parts face side seen from (Component Side) the parts face are indicated. • Indication of transistor. • A : B+ Line. • B : B– Line. • Voltage and waveforms are dc with respect to ground under no-signal (detuned) conditions. no mark : FM ∗ : Impossible to measure • Voltages are taken with a VOM (Input impedance 10 MΩ). Voltage variations may be noted due to normal produc- tion tolerances. • Waveforms are taken with a oscilloscope. Voltage variations may be noted due to normal produc- tion tolerances. • Circled numbers refer to waveforms. • Signal path. F : AUDIO f : TUNER L : VIDEO (COMPONENT) r : VIDEO (COMPOSITE) E : TAPE PLAY (DECK A) d : TAPE PLAY (DECK B) G : TAPE REC (DECK B) J : DVD (AUDIO) c : DVD (RF) I : DVD (DIGITAL) • Abbreviation E3 : 240 V AC area in E model E12 : 220 – 240 V AC area in E model E13 : 220 – 230 V AC area in E model E15 : Iran model PH : Philippine model Note: The components identified by mark 0 or dotted line with mark 0 are critical for safety. Replace only with part number specified. UNLEADED SOLDER Boards requiring use of unleaded solder are printed with the lead free mark (LF) indicating the solder contains no lead. (Caution: Some printed circuit boards may not come printed with the lead free mark due to their particular size) : LEAD FREE MARK Unleaded solder has the following characteristics. • Unleaded solder melts at a temperature about 40 °C higher than ordinary solder. Ordinary soldering irons can be used but the iron tip has to be applied to the solder joint for a slightly longer time. Soldering irons using a temperature regulator should be set to about 350 °C. Caution: The printed pattern (copper foil) may peel away if the heated tip is applied for too long, so be careful! • Strong viscosity Unleaded solder is more viscou-s (sticky, less prone to flow) than ordinary solder so use caution not to let solder bridges occur such as on IC pins, etc. • Usable with ordinary solder It is best to use only unleaded solder but unleaded solder may also be added to ordinary solder. C B These are omitted. E Q B These are omitted. C E Q B These are omitted. C E Q Note on Schematic Diagram: • All capacitors are in µF unless otherwise noted. (p: pF) 50 WV or less are not indicated except for electrolytics and tantalums. • All resistors are in Ω and 1/4 W or less unless otherwise specified. • 2 : nonflammable resistor. • C : panel designation. 1 IC102 6 (DVDRFIP) 0.5 Vp-p 200 mV/DIV, 100 nsec/DIV 500 mV/DIV, 20 µsec/DIV 2 IC102 ea (FED) 100 mV/DIV, 1 msec/DIV 6 IC102 C201 1-164-156-11 CERAMIC CHIP 0.1uF 25V C202 1-104-658-11 ELECT 100uF 20% 10V C203 1-104-658-11 ELECT 100uF 20% 10V C204 1-104-658-11 ELECT 100uF 20% 10V C205 1-104-658-11 ELECT 100uF 20% 10V C211 1-126-964-11 ELECT 10uF 20% 50V C213 1-126-964-11 ELECT 10uF 20% 50V C214 1-126-964-11 ELECT 10uF 20% 50V C218 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V C219 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V C220 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V C221 1-126-964-11 ELECT 10uF 20% 50V C222 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V C223 1-126-964-11 ELECT 10uF 20% 50V C224 1-137-194-81 FILM 0.47uF 5% 50V C225 1-137-194-81 FILM 0.47uF 5% 50V C226 1-126-960-11 ELECT 1uF 20% 50V C228 1-126-964-11 ELECT 10uF 20% 50V C236 1-130-491-00 MYLAR 0.047uF 5% 50V C237 1-126-964-11 ELECT 10uF 20% 50V C239 1-126-959-11 ELECT 0.47uF 20% 50V C251 1-126-964-11 ELECT 10uF 20% 50V C253 1-126-964-11 ELECT 10uF 20% 50V C254 1-126-964-11 ELECT 10uF 20% 50V C256 1-126-964-11 ELECT 10uF 20% 50V C258 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V C259 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V C260 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V C261 1-126-964-11 ELECT 10uF 20% 50V C262 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V C263 1-126-964-11 ELECT 10uF 20% 50V C264 1-137-194-81 FILM 0.47uF 5% 50V C265 1-137-194-81 FILM 0.47uF 5% 50V C266 1-126-960-11 ELECT 1uF 20% 50V C268 1-126-964-11 ELECT 10uF 20% 50V C273 1-126-964-11 ELECT 10uF 20% 50V C274 1-126-960-11 ELECT 1uF 20% 50V C281 1-126-964-11 ELECT 10uF 20% 50V C282 1-104-658-11 ELECT 100uF 20% 10V C283 1-164-156-11 CERAMIC CHIP 0.1uF 25V C285 1-126-961-11 ELECT 2.2uF 20% 50V C286 1-104-658-11 ELECT 100uF 20% 10V C311 1-126-964-11 ELECT 10uF 20% 50V C312 1-126-964-11 ELECT 10uF 20% 50V C316 1-126-964-11 ELECT 10uF 20% 50V C321 1-126-964-11 ELECT 10uF 20% 50V C322 1-126-964-11 ELECT 10uF 20% 50V C323 1-216-864-11 SHORT CHIP 0 C325 1-126-964-11 ELECT 10uF 20% 50V C351 1-126-964-11 ELECT 10uF 20% 50V C352 1-126-964-11 ELECT 10uF 20% 50V C356 1-126-964-11 ELECT 10uF 20% 50V C361 1-126-964-11 ELECT 10uF 20% 50V C362 1-126-964-11 ELECT 10uF 20% 50V C363 1-216-864-11 SHORT CHIP 0 C365 1-126-964-11 ELECT 10uF 20% 50V C367 1-162-927-11 CERAMIC CHIP 100PF 5% 50V C368 1-162-927-11 CERAMIC CHIP 100PF 5% 50V C601 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V C602 1-164-245-11 CERAMIC CHIP 0.015uF 10% 25V C603 1-136-155-00 FILM 0.015uF 5% 50V C604 1-126-965-11 ELECT 22uF 20% 50V C605 1-106-375-12 MYLAR 0.022uF 5% 200V C611 1-162-963-11 CERAMIC CHIP 680PF 10% 50V C612 1-100-670-11 CERAMIC CHIP 4.7uF 20% 16V C613 1-162-963-11 CERAMIC CHIP 680PF 10% 50V C614 1-126-963-11 ELECT 4.7uF 20% 50V C615 1-137-150-11 FILM 0.01uF 5% 100V C616 1-126-947-11 ELECT 47uF 20% 35V C617 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V C618 1-126-964-11 ELECT 10uF 20% 50V C619 1-136-497-81 FILM 0.1uF 5% 50V C620 1-126-960-11 ELECT 1uF 20% 50V C621 1-162-927-11 CERAMIC CHIP 100PF 5% 50V C622 1-162-927-11 CERAMIC CHIP 100PF 5% 50V C623 1-162-927-11 CERAMIC CHIP 100PF 5% 50V C624 1-162-927-11 CERAMIC CHIP 100PF 5% 50V C651 1-162-963-11 CERAMIC CHIP 680PF 10% 50V C652 1-100-670-11 CERAMIC CHIP 4.7uF 20% 16V C653 1-162-963-11 CERAMIC CHIP 680PF 10% 50V C654 1-126-963-11 ELECT 4.7uF 20% 50V C655 1-137-150-11 FILM 0.01uF 5% 100V C656 1-126-947-11 ELECT 47uF 20% 35V C657 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V C658 1-126-964-11 ELECT 10uF 20% 50V • Abbreviation E3 : 240 V AC area in E model E12 : 220 – 240 V AC area in E model E13 : 220 – 230 V AC area in E model E15 : Iran model PH : Philippine model AUDIO www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 74 HCD-GNZ5D Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark C659 1-136-497-81 FILM 0.1uF 5% 50V C725 1-107-696-11 ELECT 47uF 20% 16V C726 1-107-696-11 ELECT 47uF 20% 16V C728 1-164-156-11 CERAMIC CHIP 0.1uF 25V C753 1-119-939-51 ELECT 6800uF 20% 35V C763 1-111-235-61 ELECT 10000uF 20% 25V C764 1-126-963-11 ELECT 4.7uF 20% 50V C765 1-126-961-11 ELECT 2.2uF 20% 50V C771 1-126-956-11 ELECT 0.1uF 20% 50V C772 1-126-923-11 ELECT 220uF 20% 10V C778 1-164-156-11 CERAMIC CHIP 0.1uF 25V C791 1-126-963-11 ELECT 4.7uF 20% 50V C793 1-162-974-11 CERAMIC CHIP 0.01uF 50V C794 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V C795 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V < CONNECTOR > CN201 1-573-847-11 CONNECTOR, BOARD TO BOARD 15P CN202 1-573-847-11 CONNECTOR, BOARD TO BOARD 15P CN203 1-785-316-11 PIN, CONNECTOR (STRAIGHT) 4P CN301 1-779-285-11 CONNECTOR, FFC (LIF(NON-ZIF)) 17P CN304 1-564-506-11 PLUG, CONNECTOR 3P CN601 1-564-705-11 PIN, CONNECTOR (SMALL TYPE) 3P * CN602 1-564-710-11 PIN, CONNECTOR (SMALL TYPE) 8P CN751 1-785-322-11 PIN, CONNECTOR (STRAIGHT) 10P CN752 1-784-788-11 CONNECTOR, FFC 27P CN753 1-568-828-11 CONNECTOR, FFC 9P * CN754 1-564-518-11 PLUG, CONNECTOR 3P CN755 1-564-706-11 PIN, CONNECTOR (SMALL TYPE) 4P < DIODE > D201 6-501-193-01 DIODE 1SS355WTE-17 D202 6-501-193-01 DIODE 1SS355WTE-17 D235 6-501-193-01 DIODE 1SS355WTE-17 D271 6-500-848-01 DIODE MC2840-T112-1 D726 6-501-193-01 DIODE 1SS355WTE-17 D727 6-501-193-01 DIODE 1SS355WTE-17 D728 6-501-193-01 DIODE 1SS355WTE-17 D751 8-719-028-23 DIODE D3SBA20-4101 D753 6-500-335-01 DIODE MC2838-T112-1 D761 8-719-028-23 DIODE D3SBA20-4101 D762 6-501-193-01 DIODE 1SS355WTE-17 D763 6-500-335-01 DIODE MC2838-T112-1 D771 6-500-522-21 DIODE 10EDB40-TB3 D791 6-501-193-01 DIODE 1SS355WTE-17 D792 8-719-069-56 DIODE UDZSTE-176.2B D793 8-719-069-56 DIODE UDZSTE-176.2B < GROUND TERMINAL > EPT751 1-537-771-21 TERMINAL BOARD, GROUND < JUMPER RESISTOR > FB301 1-216-295-11 SHORT CHIP 0 < IC > IC201 6-705-667-01 IC M61537FP-RF0G IC203 6-703-610-01 IC RT8H015C-T112-1 IC771 6-703-547-01 IC TA7805LS < JUMPER RESISTOR > JR211 1-216-837-11 METAL CHIP 22K 5% 1/10W JR251 1-216-837-11 METAL CHIP 22K 5% 1/10W JR304 1-216-864-11 SHORT CHIP 0 JR305 1-216-864-11 SHORT CHIP 0 JW291 1-216-864-11 SHORT CHIP 0 JW293 1-216-864-11 SHORT CHIP 0 < COIL > L302 1-408-619-31 INDUCTOR 220uH < TRANSISTOR > Q212 8-729-905-35 TRANSISTOR 2SC4081-R Q252 8-729-905-35 TRANSISTOR 2SC4081-R Q271 8-729-905-35 TRANSISTOR 2SC4081-R Q272 8-729-905-35 TRANSISTOR 2SC4081-R Q281 8-729-905-35 TRANSISTOR 2SC4081-R Q282 8-729-905-35 TRANSISTOR 2SC4081-R Q283 8-729-905-35 TRANSISTOR 2SC4081-R Q601 8-729-011-92 TRANSISTOR 2SC2001TP-K1K2 Q602 8-729-026-53 TRANSISTOR 2SA1576A-T106-QR Q603 8-729-905-35 TRANSISTOR 2SC4081-R Q621 8-729-021-15 TRANSISTOR 2SD2351T106W Q622 8-729-021-15 TRANSISTOR 2SD2351T106W Q623 8-729-039-18 TRANSISTOR BCR183W-GEG-E6327 Q624 8-729-039-14 TRANSISTOR BCR133W-GEG-E6327 Q625 8-729-021-15 TRANSISTOR 2SD2351T106W Q626 8-729-021-15 TRANSISTOR 2SD2351T106W Q627 8-729-021-15 TRANSISTOR 2SD2351T106W Q628 8-729-021-15 TRANSISTOR 2SD2351T106W Q629 8-729-026-53 TRANSISTOR 2SA1576A-T106-QR Q630 8-729-039-14 TRANSISTOR BCR133W-GEG-E6327 Q631 8-729-039-14 TRANSISTOR BCR133W-GEG-E6327 Q701 8-729-021-15 TRANSISTOR 2SD2351T106W Q702 8-729-021-15 TRANSISTOR 2SD2351T106W Q703 8-729-021-15 TRANSISTOR 2SD2351T106W Q704 8-729-021-15 TRANSISTOR 2SD2351T106W Q721 8-729-039-18 TRANSISTOR BCR183W-GEG-E6327 Q722 8-729-039-14 TRANSISTOR BCR133W-GEG-E6327 Q723 8-729-905-35 TRANSISTOR 2SC4081-R Q728 8-729-039-18 TRANSISTOR BCR183W-GEG-E6327 Q729 8-729-039-18 TRANSISTOR BCR183W-GEG-E6327 Q771 6-550-185-01 TRANSISTOR RT1P137P-TP-1 Q772 8-729-039-14 TRANSISTOR BCR133W-GEG-E6327 Q791 8-729-039-14 TRANSISTOR BCR133W-GEG-E6327 Q792 8-729-905-35 TRANSISTOR 2SC4081-R Q793 8-729-905-35 TRANSISTOR 2SC4081-R Q794 8-729-026-68 TRANSISTOR 2SD2525(TP) Q795 8-729-039-14 TRANSISTOR BCR133W-GEG-E6327 Q797 8-729-905-35 TRANSISTOR 2SC4081-R < RESISTOR > R201 1-216-821-11 METAL CHIP 1K 5% 1/10W R202 1-216-821-11 METAL CHIP 1K 5% 1/10W R211 1-216-864-11 SHORT CHIP 0 AUDIO www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 75 HCD-GNZ5D Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark R212 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R213 1-216-833-11 METAL CHIP 10K 5% 1/10W R214 1-216-833-11 METAL CHIP 10K 5% 1/10W R215 1-216-821-11 METAL CHIP 1K 5% 1/10W R216 1-216-841-11 METAL CHIP 47K 5% 1/10W R221 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R222 1-216-825-11 METAL CHIP 2.2K 5% 1/10W 0R223 1-215-868-11 METAL OXIDE 680 5% 2W F R231 1-216-864-11 SHORT CHIP 0 R232 1-216-833-11 METAL CHIP 10K 5% 1/10W R235 1-216-837-11 METAL CHIP 22K 5% 1/10W R236 1-216-837-11 METAL CHIP 22K 5% 1/10W R237 1-216-833-11 METAL CHIP 10K 5% 1/10W R238 1-216-845-11 METAL CHIP 100K 5% 1/10W R239 1-216-857-11 METAL CHIP 1M 5% 1/10W R251 1-216-864-11 SHORT CHIP 0 R252 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R253 1-216-833-11 METAL CHIP 10K 5% 1/10W R254 1-216-833-11 METAL CHIP 10K 5% 1/10W R255 1-216-821-11 METAL CHIP 1K 5% 1/10W R256 1-216-841-11 METAL CHIP 47K 5% 1/10W R261 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R262 1-216-825-11 METAL CHIP 2.2K 5% 1/10W 0R263 1-215-868-11 METAL OXIDE 680 5% 2W F R271 1-216-821-11 METAL CHIP 1K 5% 1/10W R272 1-216-827-11 METAL CHIP 3.3K 5% 1/10W R273 1-216-837-11 METAL CHIP 22K 5% 1/10W R274 1-216-833-11 METAL CHIP 10K 5% 1/10W R275 1-216-845-11 METAL CHIP 100K 5% 1/10W R276 1-216-833-11 METAL CHIP 10K 5% 1/10W R277 1-216-841-11 METAL CHIP 47K 5% 1/10W R282 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R311 1-216-864-11 SHORT CHIP 0 R312 1-216-845-11 METAL CHIP 100K 5% 1/10W R313 1-216-864-11 SHORT CHIP 0 R315 1-216-864-11 SHORT CHIP 0 R317 1-216-864-11 SHORT CHIP 0 R321 1-216-864-11 SHORT CHIP 0 R322 1-216-845-11 METAL CHIP 100K 5% 1/10W R323 1-216-825-11 METAL CHIP 2.2K 5% 1/10W R351 1-216-864-11 SHORT CHIP 0 R352 1-216-845-11 METAL CHIP 100K 5% 1/10W R353 1-216-864-11 SHORT CHIP 0 R355 1-216-864-11 SHORT CHIP 0 R357 1-216-864-11 SHORT CHIP 0 R361 1-216-864-11 SHORT CHIP 0 R362 1-216-845-11 METAL CHIP 100K 5% 1/10W R363 1-216-825-11 METAL CHIP 2.2K 5% 1/10W R601 1-216-838-11 METAL CHIP 27K 5% 1/10W R602 1-216-295-11 SHORT CHIP 0 R603 1-216-833-11 METAL CHIP 10K 5% 1/10W R604 1-216-833-11 METAL CHIP 10K 5% 1/10W R611 1-216-821-11 METAL CHIP 1K 5% 1/10W R612 1-216-821-11 METAL CHIP 1K 5% 1/10W R613 1-216-851-11 METAL CHIP 330K 5% 1/10W R614 1-216-835-11 METAL CHIP 15K 5% 1/10W R615 1-216-812-11 METAL CHIP 180 5% 1/10W R616 1-216-834-11 METAL CHIP 12K 5% 1/10W R617 1-216-835-11 METAL CHIP 15K 5% 1/10W R618 1-216-823-11 METAL CHIP 1.5K 5% 1/10W R620 1-216-857-11 METAL CHIP 1M 5% 1/10W R621 1-216-821-11 METAL CHIP 1K 5% 1/10W R622 1-216-821-11 METAL CHIP 1K 5% 1/10W R623 1-216-821-11 METAL CHIP 1K 5% 1/10W R624 1-216-821-11 METAL CHIP 1K 5% 1/10W R625 1-216-821-11 METAL CHIP 1K 5% 1/10W R626 1-216-821-11 METAL CHIP 1K 5% 1/10W R627 1-216-833-11 METAL CHIP 10K 5% 1/10W R628 1-216-833-11 METAL CHIP 10K 5% 1/10W R629 1-216-833-11 METAL CHIP 10K 5% 1/10W R632 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R639 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R651 1-216-821-11 METAL CHIP 1K 5% 1/10W R652 1-216-821-11 METAL CHIP 1K 5% 1/10W R653 1-216-851-11 METAL CHIP 330K 5% 1/10W R654 1-216-835-11 METAL CHIP 15K 5% 1/10W R655 1-216-812-11 METAL CHIP 180 5% 1/10W R656 1-216-834-11 METAL CHIP 12K 5% 1/10W R657 1-216-835-11 METAL CHIP 15K 5% 1/10W R658 1-216-823-11 METAL CHIP 1.5K 5% 1/10W R659 1-216-797-11 METAL CHIP 10 5% 1/10W R701 1-216-825-11 METAL CHIP 2.2K 5% 1/10W R702 1-216-825-11 METAL CHIP 2.2K 5% 1/10W R703 1-216-821-11 METAL CHIP 1K 5% 1/10W R704 1-216-821-11 METAL CHIP 1K 5% 1/10W R715 1-216-864-11 SHORT CHIP 0 R717 1-216-864-11 SHORT CHIP 0 R721 1-216-821-11 METAL CHIP 1K 5% 1/10W R723 1-216-821-11 METAL CHIP 1K 5% 1/10W R737 1-216-833-11 METAL CHIP 10K 5% 1/10W R738 1-216-864-11 SHORT CHIP 0 R739 1-216-841-11 METAL CHIP 47K 5% 1/10W R740 1-216-833-11 METAL CHIP 10K 5% 1/10W R741 1-216-864-11 SHORT CHIP 0 R742 1-216-841-11 METAL CHIP 47K 5% 1/10W R751 1-216-809-11 METAL CHIP 100 5% 1/10W R752 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R753 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R762 1-216-837-11 METAL CHIP 22K 5% 1/10W R763 1-216-837-11 METAL CHIP 22K 5% 1/10W R764 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W R768 1-216-809-11 METAL CHIP 100 5% 1/10W R769 1-216-809-11 METAL CHIP 100 5% 1/10W R790 1-216-809-11 METAL CHIP 100 5% 1/10W R791 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R792 1-216-841-11 METAL CHIP 47K 5% 1/10W R793 1-216-849-11 METAL CHIP 220K 5% 1/10W R794 1-216-837-11 METAL CHIP 22K 5% 1/10W R795 1-216-837-11 METAL CHIP 22K 5% 1/10W R796 1-216-833-11 METAL CHIP 10K 5% 1/10W R798 1-216-809-11 METAL CHIP 100 5% 1/10W < TRANSFORMER > T601 1-437-220-11 TRANSFORMER, BIAS OSCILLATION ************************************************************* AUDIO www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 76 HCD-GNZ5D Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark A-1109-316-A DMB11 BOARD, COMPLETE (PH) A-1109-317-A DMB11 BOARD, COMPLETE (EXCEPT PH) *********************** < CAPACITOR > C101 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C102 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C105 1-126-205-11 ELECT CHIP 47uF 20% 6.3V C106 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C108 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C109 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C112 1-126-205-11 ELECT CHIP 47uF 20% 6.3V C113 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C114 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C115 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C116 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C117 1-124-779-00 ELECT CHIP 10uF 20% 16V C118 1-124-779-00 ELECT CHIP 10uF 20% 16V C119 1-124-779-00 ELECT CHIP 10uF 20% 16V C120 1-165-908-11 CERAMIC CHIP 1uF 10% 10V C121 1-165-908-11 CERAMIC CHIP 1uF 10% 10V C122 1-165-908-11 CERAMIC CHIP 1uF 10% 10V C123 1-165-908-11 CERAMIC CHIP 1uF 10% 10V C124 1-165-908-11 CERAMIC CHIP 1uF 10% 10V C125 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C126 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C127 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C128 1-162-965-11 CERAMIC CHIP 0.0015uF 10% 50V C129 1-124-779-00 ELECT CHIP 10uF 20% 16V C130 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C131 1-125-838-11 CERAMIC CHIP 2.2uF 10% 6.3V C132 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C133 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C135 1-164-677-11 CERAMIC CHIP 0.033uF 10% 16V C136 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C137 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C138 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C139 1-162-919-11 CERAMIC CHIP 22PF 5% 50V C140 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C144 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C146 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C147 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V C148 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V C149 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C150 1-124-779-00 ELECT CHIP 10uF 20% 16V C151 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V C152 1-162-916-11 CERAMIC CHIP 12PF 5% 50V C153 1-162-916-11 CERAMIC CHIP 12PF 5% 50V C154 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C155 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C156 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C158 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C159 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C160 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C161 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C162 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C163 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C164 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C167 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C170 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C171 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C172 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C173 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C174 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C175 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C176 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C177 1-126-205-11 ELECT CHIP 47uF 20% 6.3V C178 1-126-208-21 ELECT CHIP 47uF 20% 4V C179 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C180 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C181 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C182 1-127-715-11 CERAMIC CHIP 0.22uF 10% 16V C184 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C187 1-126-208-21 ELECT CHIP 47uF 20% 4V C188 1-127-715-11 CERAMIC CHIP 0.22uF 10% 16V C189 1-128-934-11 CERAMIC CHIP 0.33uF 20% 10V C190 1-126-205-11 ELECT CHIP 47uF 20% 6.3V C191 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C192 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C193 1-127-715-11 CERAMIC CHIP 0.22uF 10% 16V C195 1-127-715-11 CERAMIC CHIP 0.22uF 10% 16V C196 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V C203 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C205 1-164-230-11 CERAMIC CHIP 220PF 5% 50V C206 1-164-230-11 CERAMIC CHIP 220PF 5% 50V C208 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C209 1-164-677-11 CERAMIC CHIP 0.033uF 10% 16V C210 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C211 1-164-677-11 CERAMIC CHIP 0.033uF 10% 16V C212 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C213 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C214 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C215 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C217 1-126-204-11 ELECT CHIP 47uF 20% 16V C218 1-124-779-00 ELECT CHIP 10uF 20% 16V C219 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C220 1-124-779-00 ELECT CHIP 10uF 20% 16V C221 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C222 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C224 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C233 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V C301 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C302 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V C305 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V C306 1-126-206-11 ELECT CHIP 100uF 20% 6.3V C307 1-126-206-11 ELECT CHIP 100uF 20% 6.3V C402 1-126-204-11 ELECT CHIP 47uF 20% 16V C403 1-126-205-11 ELECT CHIP 47uF 20% 6.3V C3701 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C3702 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C3707 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C3708 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C3711 1-162-977-11 CERAMIC CHIP 0.0018uF 10% 50V C3712 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V C3713 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C3714 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V DMB11 Ver. 1.1 New part of EEP ROM (IC103) on the DMB11 board cannot be used. Therefore, if the mounted DMB11 board (A-1109-317-A, etc.) is replaced, exchange new EEP ROM (IC103) with that used before the replacement. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 77 HCD-GNZ5D Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark C3721 1-162-977-11 CERAMIC CHIP 0.0018uF 10% 50V C3722 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V C3723 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C3724 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C3771 1-162-977-11 CERAMIC CHIP 0.0018uF 10% 50V C3772 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V C3773 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C3774 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C3781 1-162-977-11 CERAMIC CHIP 0.0018uF 10% 50V C3782 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V C3783 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C3784 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C3801 1-126-206-11 ELECT CHIP 100uF 20% 6.3V C3802 1-117-370-11 CERAMIC CHIP 10uF 10V C3803 1-126-205-11 ELECT CHIP 47uF 20% 6.3V C3804 1-126-205-11 ELECT CHIP 47uF 20% 6.3V C3805 1-126-208-21 ELECT CHIP 47uF 20% 4V < CONNECTOR > CN101 1-815-763-32 CONNECTOR, FFC/FPC 24P * CN105 1-770-470-21 PIN, CONNECTOR (PC BOARD) 6P CN106 1-793-989-21 CONNECTOR, FFC/FPC 13P * CN201 1-770-470-21 PIN, CONNECTOR (PC BOARD) 6P CN301 1-784-365-21 CONNECTOR, FFC/FPC 5P CN302 1-784-376-11 CONNECTOR, FFC/FPC 17P CN401 1-779-993-11 PIN, CONNECTOR (PWB) 5P < DIODE > D1001 8-719-058-24 DIODE RB501V-40TE-17 D3501 6-501-193-01 DIODE 1SS355WTE-17 D3502 6-501-193-01 DIODE 1SS355WTE-17 < FERRITE BEAD > FB111 1-414-226-21 INDUCTOR, FERRITE BEAD FB112 1-414-226-21 INDUCTOR, FERRITE BEAD FB113 1-414-226-21 INDUCTOR, FERRITE BEAD FB114 1-414-226-21 INDUCTOR, FERRITE BEAD FB115 1-414-226-21 INDUCTOR, FERRITE BEAD FB401 1-469-324-21 FERRITE, EMI (SMD) (2012) FB402 1-469-324-21 FERRITE, EMI (SMD) (2012) FB403 1-469-324-21 FERRITE, EMI (SMD) (2012) FB404 1-469-324-21 FERRITE, EMI (SMD) (2012) FB405 1-469-324-21 FERRITE, EMI (SMD) (2012) FB406 1-469-324-21 FERRITE, EMI (SMD) (2012) < FILTER > FL101 1-234-177-21 FILTER, CHIP EMI FL104 1-234-177-21 FILTER, CHIP EMI FL105 1-234-177-21 FILTER, CHIP EMI FL106 1-234-177-21 FILTER, CHIP EMI FL107 1-234-177-21 FILTER, CHIP EMI FL108 1-234-177-21 FILTER, CHIP EMI FL401 1-234-177-21 FILTER, CHIP EMI FL402 1-233-893-21 FILTER, CHIP EMI FL403 1-234-177-21 FILTER, CHIP EMI < IC > IC101 6-805-764-01 IC MX29LV320ABTC65-CBA4-0503CE (EXCEPT PH) IC101 6-805-765-01 IC MX29LV320ABTC65-CBA4-0503GA (PH) IC102 6-707-535-01 IC CXD9849R IC103 (not supplied) IC BR24L64F-WE2 IC104 6-705-929-01 IC K4S641632H-UC75T IC105 6-702-302-01 IC TK11133CSCL-G IC106 6-708-153-01 IC PQ018EN01ZPH IC107 6-702-302-01 IC TK11133CSCL-G IC201 6-704-524-01 IC FAN8036L IC301 6-704-222-01 IC AK4358VQ-L IC3711 8-759-359-49 IC NJM3414AV(TE2) IC3771 8-759-359-49 IC NJM3414AV(TE2) < TRANSISTOR > Q101 6-550-008-01 FET UM6K1N-TN Q102 6-550-653-01 FET QST8TR Q103 8-729-901-00 TRANSISTOR DTC124EK Q3801 8-729-230-49 TRANSISTOR 2SC2712-YG < RESISTOR > R101 1-216-809-11 METAL CHIP 100 5% 1/10W R104 1-216-864-11 SHORT CHIP 0 R105 1-216-833-11 METAL CHIP 10K 5% 1/10W R106 1-216-833-11 METAL CHIP 10K 5% 1/10W R107 1-216-833-11 METAL CHIP 10K 5% 1/10W R108 1-216-857-11 METAL CHIP 1M 5% 1/10W R109 1-216-864-11 SHORT CHIP 0 R110 1-216-841-11 METAL CHIP 47K 5% 1/10W R111 1-216-809-11 METAL CHIP 100 5% 1/10W R112 1-211-977-11 METAL CHIP 22 0.5% 1/10W R113 1-211-977-11 METAL CHIP 22 0.5% 1/10W R114 1-216-845-11 METAL CHIP 100K 5% 1/10W R115 1-211-977-11 METAL CHIP 22 0.5% 1/10W R116 1-216-821-11 METAL CHIP 1K 5% 1/10W R117 1-216-841-11 METAL CHIP 47K 5% 1/10W R118 1-216-801-11 METAL CHIP 22 5% 1/10W R120 1-216-801-11 METAL CHIP 22 5% 1/10W R121 1-216-801-11 METAL CHIP 22 5% 1/10W R123 1-216-864-11 SHORT CHIP 0 R124 1-216-841-11 METAL CHIP 47K 5% 1/10W R126 1-216-864-11 SHORT CHIP 0 R127 1-216-809-11 METAL CHIP 100 5% 1/10W R136 1-216-835-11 METAL CHIP 15K 5% 1/10W R138 1-216-845-11 METAL CHIP 100K 5% 1/10W R141 1-218-916-11 METAL CHIP 750K 0.5% 1/10W R142 1-216-845-11 METAL CHIP 100K 5% 1/10W R143 1-469-116-21 FERRITE, EMI (SMD) (1608) R144 1-216-864-11 SHORT CHIP 0 R146 1-216-805-11 METAL CHIP 47 5% 1/10W R151 1-216-805-11 METAL CHIP 47 5% 1/10W R152 1-216-864-11 SHORT CHIP 0 R153 1-216-805-11 METAL CHIP 47 5% 1/10W R155 1-216-805-11 METAL CHIP 47 5% 1/10W R160 1-216-805-11 METAL CHIP 47 5% 1/10W R161 1-216-809-11 METAL CHIP 100 5% 1/10W DMB11 Ver. 1.1 New part of EEP ROM (IC103) on the DMB11 board cannot be used. Therefore, if the mounted DMB11 board (A-1109-317-A, etc.) is replaced, exchange new EEP ROM (IC103) with that used before the replacement. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 78 HCD-GNZ5D Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark R164 1-216-809-11 METAL CHIP 100 5% 1/10W R169 1-216-833-11 METAL CHIP 10K 5% 1/10W R187 1-216-864-11 SHORT CHIP 0 R189 1-218-827-11 METAL CHIP 150 0.5% 1/10W R190 1-218-827-11 METAL CHIP 150 0.5% 1/10W R191 1-216-821-11 METAL CHIP 1K 5% 1/10W R192 1-218-827-11 METAL CHIP 150 0.5% 1/10W R193 1-216-821-11 METAL CHIP 1K 5% 1/10W R195 1-218-827-11 METAL CHIP 150 0.5% 1/10W R196 1-216-864-11 SHORT CHIP 0 R197 1-218-827-11 METAL CHIP 150 0.5% 1/10W R204 1-216-822-11 METAL CHIP 1.2K 5% 1/10W R205 1-216-833-11 METAL CHIP 10K 5% 1/10W R206 1-216-833-11 METAL CHIP 10K 5% 1/10W R207 1-216-826-11 METAL CHIP 2.7K 5% 1/10W R208 1-216-839-11 METAL CHIP 33K 5% 1/10W R209 1-216-839-11 METAL CHIP 33K 5% 1/10W R210 1-216-841-11 METAL CHIP 47K 5% 1/10W R212 1-216-833-11 METAL CHIP 10K 5% 1/10W R213 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W R214 1-216-835-11 METAL CHIP 15K 5% 1/10W R215 1-216-834-11 METAL CHIP 12K 5% 1/10W R216 1-216-834-11 METAL CHIP 12K 5% 1/10W R219 1-216-838-11 METAL CHIP 27K 5% 1/10W R220 1-216-833-11 METAL CHIP 10K 5% 1/10W R221 1-218-889-11 METAL CHIP 56K 0.5% 1/10W R223 1-218-895-11 METAL CHIP 100K 0.5% 1/10W R224 1-216-833-11 METAL CHIP 10K 5% 1/10W R225 1-218-895-11 METAL CHIP 100K 0.5% 1/10W R226 1-218-889-11 METAL CHIP 56K 0.5% 1/10W R230 1-218-893-11 METAL CHIP 82K 0.5% 1/10W R231 1-218-875-11 METAL CHIP 15K 0.5% 1/10W R232 1-218-877-11 METAL CHIP 18K 0.5% 1/10W R233 1-218-883-11 METAL CHIP 33K 0.5% 1/10W R234 1-216-833-11 METAL CHIP 10K 5% 1/10W R246 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R247 1-216-821-11 METAL CHIP 1K 5% 1/10W R314 1-216-809-11 METAL CHIP 100 5% 1/10W R318 1-216-864-11 SHORT CHIP 0 R319 1-216-864-11 SHORT CHIP 0 R321 1-216-864-11 SHORT CHIP 0 R1101 1-216-825-11 METAL CHIP 2.2K 5% 1/10W R1102 1-218-827-11 METAL CHIP 150 0.5% 1/10W R1103 1-216-833-11 METAL CHIP 10K 5% 1/10W R1104 1-216-833-11 METAL CHIP 10K 5% 1/10W R1105 1-216-833-11 METAL CHIP 10K 5% 1/10W R1108 1-216-864-11 SHORT CHIP 0 R1109 1-216-864-11 SHORT CHIP 0 R1110 1-216-826-11 METAL CHIP 2.7K 5% 1/10W R1123 1-216-864-11 SHORT CHIP 0 R1126 1-216-833-11 METAL CHIP 10K 5% 1/10W R1129 1-216-845-11 METAL CHIP 100K 5% 1/10W R1133 1-216-864-11 SHORT CHIP 0 R1134 1-216-864-11 SHORT CHIP 0 R1150 1-216-827-11 METAL CHIP 3.3K 5% 1/10W R1151 1-216-827-11 METAL CHIP 3.3K 5% 1/10W R1152 1-216-827-11 METAL CHIP 3.3K 5% 1/10W R1168 1-216-817-11 METAL CHIP 470 5% 1/10W R1502 1-216-864-11 SHORT CHIP 0 R1504 1-216-864-11 SHORT CHIP 0 R1524 1-216-864-11 SHORT CHIP 0 R1526 1-216-864-11 SHORT CHIP 0 R1530 1-216-864-11 SHORT CHIP 0 R1531 1-216-864-11 SHORT CHIP 0 R1540 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R1542 1-216-833-11 METAL CHIP 10K 5% 1/10W R1543 1-216-833-11 METAL CHIP 10K 5% 1/10W R1544 1-216-864-11 SHORT CHIP 0 R1546 1-216-827-11 METAL CHIP 3.3K 5% 1/10W R1547 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R1548 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R1549 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R1550 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R1551 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R1552 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R1553 1-216-864-11 SHORT CHIP 0 R1554 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R1557 1-216-809-11 METAL CHIP 100 5% 1/10W R2504 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R3501 1-216-809-11 METAL CHIP 100 5% 1/10W R3652 1-216-864-11 SHORT CHIP 0 R3653 1-216-864-11 SHORT CHIP 0 R3711 1-218-271-11 METAL CHIP 2K 5% 1/10W R3712 1-218-271-11 METAL CHIP 2K 5% 1/10W R3713 1-216-827-11 METAL CHIP 3.3K 5% 1/10W R3714 1-216-827-11 METAL CHIP 3.3K 5% 1/10W R3715 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R3716 1-216-821-11 METAL CHIP 1K 5% 1/10W R3717 1-216-821-11 METAL CHIP 1K 5% 1/10W R3718 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R3719 1-216-821-11 METAL CHIP 1K 5% 1/10W R3721 1-218-271-11 METAL CHIP 2K 5% 1/10W R3722 1-218-271-11 METAL CHIP 2K 5% 1/10W R3723 1-216-827-11 METAL CHIP 3.3K 5% 1/10W R3724 1-216-827-11 METAL CHIP 3.3K 5% 1/10W R3725 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R3726 1-216-821-11 METAL CHIP 1K 5% 1/10W R3727 1-216-821-11 METAL CHIP 1K 5% 1/10W R3728 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R3729 1-216-821-11 METAL CHIP 1K 5% 1/10W R3771 1-218-271-11 METAL CHIP 2K 5% 1/10W R3772 1-218-271-11 METAL CHIP 2K 5% 1/10W R3773 1-216-827-11 METAL CHIP 3.3K 5% 1/10W R3774 1-216-827-11 METAL CHIP 3.3K 5% 1/10W R3775 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R3776 1-216-821-11 METAL CHIP 1K 5% 1/10W R3777 1-216-821-11 METAL CHIP 1K 5% 1/10W R3778 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R3779 1-216-821-11 METAL CHIP 1K 5% 1/10W R3781 1-218-271-11 METAL CHIP 2K 5% 1/10W R3782 1-218-271-11 METAL CHIP 2K 5% 1/10W R3783 1-216-827-11 METAL CHIP 3.3K 5% 1/10W R3784 1-216-827-11 METAL CHIP 3.3K 5% 1/10W R3785 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R3786 1-216-821-11 METAL CHIP 1K 5% 1/10W R3787 1-216-821-11 METAL CHIP 1K 5% 1/10W DMB11 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 79 HCD-GNZ5D Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark R3788 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R3789 1-216-821-11 METAL CHIP 1K 5% 1/10W R3801 1-216-864-11 SHORT CHIP 0 R3802 1-216-864-11 SHORT CHIP 0 R3803 1-216-833-11 METAL CHIP 10K 5% 1/10W R3804 1-216-836-11 METAL CHIP 18K 5% 1/10W R3805 1-216-821-11 METAL CHIP 1K 5% 1/10W R4701 1-216-864-11 SHORT CHIP 0 R4702 1-216-864-11 SHORT CHIP 0 R4703 1-216-864-11 SHORT CHIP 0 R4704 1-216-864-11 SHORT CHIP 0 R4705 1-216-864-11 SHORT CHIP 0 R4706 1-216-864-11 SHORT CHIP 0 R5005 1-216-864-11 SHORT CHIP 0 R5011 1-216-864-11 SHORT CHIP 0 R5016 1-216-864-11 SHORT CHIP 0 (EXCEPT PH) R5017 1-216-864-11 SHORT CHIP 0 (PH) < NETWORK RESISTOR > RB103 1-234-795-21 RES, NETWORK 0X4 (2010) RB104 1-234-795-21 RES, NETWORK 0X4 (2010) RB105 1-234-371-21 RES, NETWORK 47X4 (1005) RB106 1-234-371-21 RES, NETWORK 47X4 (1005) RB107 1-234-370-21 RES, NETWORK 22X4 (1005) RB108 1-234-370-21 RES, NETWORK 22X4 (1005) RB111 1-234-795-21 RES, NETWORK 0X4 (2010) RB112 1-234-370-21 RES, NETWORK 22X4 (1005) RB113 1-234-370-21 RES, NETWORK 22X4 (1005) < VIBRATOR > X101 1-781-867-21 VIBRATOR, CRYSTAL (27MHz) ************************************************************* A-1103-756-A DRIVER BOARD, COMPLETE *********************** < CAPACITOR > C715 1-126-933-11 ELECT 100uF 20% 16V C731 1-126-964-11 ELECT 10uF 20% 50V C735 1-164-159-21 CERAMIC 0.1uF 50V C736 1-164-159-21 CERAMIC 0.1uF 50V C737 1-164-159-21 CERAMIC 0.1uF 50V C741 1-162-306-11 CERAMIC 0.01uF 20% 16V C751 1-162-306-11 CERAMIC 0.01uF 20% 16V C752 1-164-159-21 CERAMIC 0.1uF 50V < CONNECTOR > CN701 1-784-735-11 CONNECTOR, FFC 13P CN702 1-784-766-11 CONNECTOR, FFC 5P * CN703 1-564-720-11 PIN, CONNECTOR (SMALL TYPE) 4P CN704 1-785-328-11 PIN, CONNECTOR (LIGHT ANGLE) 2P < DIODE > D701 8-719-921-42 DIODE MTZJ-5.1A D711 8-719-109-69 DIODE RD3.6ESB2 < IC > IC701 8-759-598-69 IC BA6956AN IC712 8-759-598-69 IC BA6956AN < TRANSISTOR > Q731 8-729-029-66 TRANSISTOR DTC114ESA < RESISTOR > R701 1-249-413-11 CARBON 470 5% 1/4W R702 1-247-807-31 CARBON 100 5% 1/4W R711 1-249-417-11 CARBON 1K 5% 1/4W R712 1-249-425-11 CARBON 4.7K 5% 1/4W R713 1-249-433-11 CARBON 22K 5% 1/4W R721 1-249-425-11 CARBON 4.7K 5% 1/4W R722 1-249-425-11 CARBON 4.7K 5% 1/4W R723 1-249-425-11 CARBON 4.7K 5% 1/4W R731 1-247-807-31 CARBON 100 5% 1/4W R732 1-249-429-11 CARBON 10K 5% 1/4W R733 1-249-417-11 CARBON 1K 5% 1/4W R734 1-249-430-11 CARBON 12K 5% 1/4W R735 1-247-807-31 CARBON 100 5% 1/4W R751 1-249-425-11 CARBON 4.7K 5% 1/4W ************************************************************* A-1109-314-A FRONT AMP BOARD, COMPLETE *************************** 7-685-872-09 SCREW +BVTT 3X8 (S) < CAPACITOR > C401 1-126-964-11 ELECT 10uF 20% 50V C402 1-162-302-11 CERAMIC 0.0022uF 20% 16V C403 1-162-286-31 CERAMIC 220PF 10% 50V C404 1-126-967-11 ELECT 47uF 20% 50V C406 1-136-495-11 FILM 0.068uF 5% 50V C407 1-136-495-11 FILM 0.068uF 5% 50V C408 1-126-968-11 ELECT 100uF 20% 50V C410 1-126-926-11 ELECT 1000uF 20% 10V C416 1-162-306-11 CERAMIC 0.01uF 20% 16V C421 1-128-575-11 ELECT 33uF 20% 63V C451 1-126-964-11 ELECT 10uF 20% 50V C452 1-162-302-11 CERAMIC 0.0022uF 20% 16V C453 1-162-286-31 CERAMIC 220PF 10% 50V C454 1-126-967-11 ELECT 47uF 20% 50V C456 1-136-495-11 FILM 0.068uF 5% 50V C457 1-136-495-11 FILM 0.068uF 5% 50V C458 1-126-968-11 ELECT 100uF 20% 50V C471 1-135-832-11 ELECT 2200uF 20% 50V C472 1-135-832-11 ELECT 2200uF 20% 50V C485 1-162-306-11 CERAMIC 0.01uF 20% 16V C486 1-162-306-11 CERAMIC 0.01uF 20% 16V C941 1-126-956-11 ELECT 0.1uF 20% 50V C942 1-126-925-11 ELECT 470uF 20% 10V C943 1-126-956-11 ELECT 0.1uF 20% 50V C944 1-104-658-11 ELECT 100uF 20% 10V C945 1-126-956-11 ELECT 0.1uF 20% 50V C946 1-104-658-11 ELECT 100uF 20% 10V C949 1-126-947-11 ELECT 47uF 20% 35V C950 1-104-658-11 ELECT 100uF 20% 10V DMB11 DRIVER FRONT AMP www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 80 HCD-GNZ5D Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark < CONNECTOR > CN401 1-573-829-11 CONNECTOR, BOARD TO BOARD 15P CN402 1-573-829-11 CONNECTOR, BOARD TO BOARD 15P < DIODE > D401 8-719-991-33 DIODE 1SS133T-77 D410 8-719-210-21 DIODE 11EQS04 D451 8-719-991-33 DIODE 1SS133T-77 D471 8-719-510-68 DIODE D5SBA204101 D481 8-719-991-33 DIODE 1SS133T-77 D485 8-719-991-33 DIODE 1SS133T-77 D486 8-719-991-33 DIODE 1SS133T-77 D491 8-719-991-33 DIODE 1SS133T-77 < IC > IC401 6-705-845-01 IC STK403-090 < TRANSISTOR > Q401 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA Q402 8-729-140-82 TRANSISTOR 2SA988-PAFAEA Q403 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA Q416 8-729-119-78 TRANSISTOR 2SC2785-HFE Q417 8-729-119-78 TRANSISTOR 2SC2785-HFE Q451 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA Q481 8-729-140-82 TRANSISTOR 2SA988-PAFAEA Q482 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA < RESISTOR > R401 1-247-831-11 CARBON 1K 5% 1/4W R402 1-247-871-11 CARBON 47K 5% 1/4W R403 1-247-812-11 CARBON 160 5% 1/4W R404 1-247-871-11 CARBON 47K 5% 1/4W 0R406 1-208-602-11 METAL 0.22X2 2W R407 1-247-831-11 CARBON 1K 5% 1/4W R408 1-249-431-11 CARBON 15K 5% 1/4W R409 1-247-879-11 CARBON 100K 5% 1/4W R410 1-260-076-11 CARBON 10 5% 1/2W F 0R411 1-212-881-11 FUSIBLE 100 5% 1/4W F R412 1-247-887-00 CARBON 220K 5% 1/4W R413 1-249-421-11 CARBON 2.2K 5% 1/4W R415 1-249-429-11 CARBON 10K 5% 1/4W R416 1-249-429-11 CARBON 10K 5% 1/4W R417 1-249-429-11 CARBON 10K 5% 1/4W R418 1-247-871-11 CARBON 47K 5% 1/4W 0R419 1-202-972-61 FUSIBLE 1 5% 1/4W F 0R420 1-202-972-61 FUSIBLE 1 5% 1/4W F R421 1-249-429-11 CARBON 10K 5% 1/4W R425 1-249-439-11 CARBON 68K 5% 1/4W R426 1-249-426-11 CARBON 5.6K 5% 1/4W R427 1-249-421-11 CARBON 2.2K 5% 1/4W R428 1-247-863-11 CARBON 22K 5% 1/4W R429 1-249-429-11 CARBON 10K 5% 1/4W R430 1-249-429-11 CARBON 10K 5% 1/4W R439 1-247-871-11 CARBON 47K 5% 1/4W R440 1-247-873-11 CARBON 56K 5% 1/4W R451 1-247-831-11 CARBON 1K 5% 1/4W R452 1-247-871-11 CARBON 47K 5% 1/4W R453 1-247-812-11 CARBON 160 5% 1/4W R454 1-247-871-11 CARBON 47K 5% 1/4W 0R456 1-208-602-11 METAL 0.22X2 2W R457 1-247-831-11 CARBON 1K 5% 1/4W R458 1-249-431-11 CARBON 15K 5% 1/4W R459 1-247-879-11 CARBON 100K 5% 1/4W R460 1-260-076-11 CARBON 10 5% 1/2W F 0R461 1-212-881-11 FUSIBLE 100 5% 1/4W F R471 1-247-879-11 CARBON 100K 5% 1/4W R472 1-247-879-11 CARBON 100K 5% 1/4W 0R480 1-215-890-11 METAL OXIDE 470 5% 2W F R485 1-247-871-11 CARBON 47K 5% 1/4W R486 1-247-871-11 CARBON 47K 5% 1/4W R487 1-249-429-11 CARBON 10K 5% 1/4W R488 1-247-871-11 CARBON 47K 5% 1/4W R489 1-249-429-11 CARBON 10K 5% 1/4W R490 1-249-429-11 CARBON 10K 5% 1/4W R941 1-247-831-11 CARBON 1K 5% 1/4W < RELAY > RY481 1-515-920-11 RELAY (24V) < THERMISTOR > TH401 1-807-796-11 THERMISTOR < TERMINAL BOARD > TM401 1-694-677-12 TERMINAL BOARD (4P) (FRONT SPEAKER) ************************************************************* A-1109-321-A JACK BOARD, COMPLETE ********************* < CAPACITOR > C1005 1-115-872-11 ELECT 2.2uF 20% 50V C1006 1-162-955-11 CERAMIC CHIP 150PF 5% 50V C1007 1-126-786-11 ELECT 47uF 20% 16V C1008 1-162-949-11 CERAMIC CHIP 47PF 5% 50V C1009 1-115-872-11 ELECT 2.2uF 20% 50V C1010 1-115-867-11 ELECT 0.1uF 20% 50V C1011 1-162-962-11 CERAMIC CHIP 470PF 10% 50V C1012 1-126-786-11 ELECT 47uF 20% 16V C1013 1-162-949-11 CERAMIC CHIP 47PF 5% 50V C1014 1-115-868-11 ELECT 0.22uF 20% 50V C1016 1-107-726-11 CERAMIC CHIP 0.01uF 10% 16V C1036 1-164-360-11 CERAMIC CHIP 0.1uF 16V < DIODE > D1005 6-501-193-01 DIODE 1SS355WTE-17 D1006 6-501-193-01 DIODE 1SS355WTE-17 < GROUND TERMINAL > EPT1001 1-537-771-21 TERMINAL BOARD, GROUND EPT1002 1-537-771-21 TERMINAL BOARD, GROUND < JUMPER RESISTOR > FB1003 1-216-295-11 SHORT CHIP 0 FB1004 1-216-295-11 SHORT CHIP 0 FRONT AMP JACK www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 81 HCD-GNZ5D Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark < IC > IC1001 8-759-710-97 IC NJM4565M-D < JACK > J1002 1-770-226-11 JACK (LARGE TYPE) (MIC) J1004 1-794-702-11 JACK, HEADPHONE (PHONES) < JUMPER RESISTOR > JR1000 1-216-295-11 SHORT CHIP 0 < RESISTOR > R1006 1-216-845-11 METAL CHIP 100K 5% 1/10W R1007 1-216-813-11 METAL CHIP 220 5% 1/10W R1008 1-216-809-11 METAL CHIP 100 5% 1/10W R1009 1-216-830-11 METAL CHIP 5.6K 5% 1/10W R1010 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R1011 1-216-847-11 METAL CHIP 150K 5% 1/10W R1012 1-216-833-11 METAL CHIP 10K 5% 1/10W R1013 1-216-809-11 METAL CHIP 100 5% 1/10W R1014 1-216-851-11 METAL CHIP 330K 5% 1/10W R1015 1-216-835-11 METAL CHIP 15K 5% 1/10W R1017 1-216-833-11 METAL CHIP 10K 5% 1/10W R1019 1-216-864-11 SHORT CHIP 0 R1020 1-216-864-11 SHORT CHIP 0 R1031 1-260-083-11 CARBON 47 5% 1/2W R1032 1-260-083-11 CARBON 47 5% 1/2W < VARIABLE RESISTOR > RV1001 1-223-983-11 RES, VAR, CARBON 50K (MIC LEVEL) ************************************************************* 1-687-133-12 MOTOR (LD) BOARD ***************** ************************************************************* 1-687-134-12 MOTOR (TB) BOARD ***************** < CONNECTOR > CN742 1-784-727-11 CONNECTOR, FFC 5P ************************************************************* OPTICAL BOARD ************** < CAPACITOR > C308 1-164-156-11 CERAMIC CHIP 0.1uF 25V C309 1-126-923-11 ELECT 220uF 20% 10V < IC > IC306 6-600-465-11 IC TOTX147 (DIGITAL OUT OPTICAL) < JUMPER RESISTOR > R304 1-216-864-11 SHORT CHIP 0 ************************************************************* A-1141-196-A PANEL BOARD, COMPLETE ********************** < CAPACITOR > C101 1-164-156-11 CERAMIC CHIP 0.1uF 25V C102 1-164-156-11 CERAMIC CHIP 0.1uF 25V C103 1-126-916-11 ELECT 1000uF 20% 6.3V C104 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C105 1-119-941-11 ELECT 470uF 20% 6.3V C106 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C110 1-162-918-11 CERAMIC CHIP 18PF 5% 50V C111 1-162-919-11 CERAMIC CHIP 22PF 5% 50V C112 1-164-156-11 CERAMIC CHIP 0.1uF 25V C113 1-162-974-11 CERAMIC CHIP 0.01uF 50V C114 1-162-974-11 CERAMIC CHIP 0.01uF 50V C115 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V C116 1-162-953-11 CERAMIC CHIP 100PF 5% 50V C117 1-162-953-11 CERAMIC CHIP 100PF 5% 50V C118 1-162-953-11 CERAMIC CHIP 100PF 5% 50V C119 1-162-953-11 CERAMIC CHIP 100PF 5% 50V C120 1-162-953-11 CERAMIC CHIP 100PF 5% 50V C121 1-119-941-11 ELECT 470uF 20% 6.3V C122 1-119-941-11 ELECT 470uF 20% 6.3V C125 1-162-974-11 CERAMIC CHIP 0.01uF 50V C126 1-119-943-11 ELECT 47uF 20% 50V C127 1-162-974-11 CERAMIC CHIP 0.01uF 50V C128 1-126-382-11 ELECT 100uF 20% 16V C129 1-162-953-11 CERAMIC CHIP 100PF 5% 50V C130 1-162-953-11 CERAMIC CHIP 100PF 5% 50V C144 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V C145 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C146 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C147 1-126-382-11 ELECT 100uF 20% 16V C152 1-162-953-11 CERAMIC CHIP 100PF 5% 50V C153 1-162-953-11 CERAMIC CHIP 100PF 5% 50V C154 1-162-953-11 CERAMIC CHIP 100PF 5% 50V < CONNECTOR > * CN001 1-568-450-11 HOUSING, CONNECTOR (PC BOARD) 4P * CN002 1-568-451-11 HOUSING, CONNECTOR (PC BOARD) 10P CN003 1-784-749-11 CONNECTOR, FFC 27P CN004 1-784-735-11 CONNECTOR, FFC 13P CN005 1-779-550-21 CONNECTOR, FFC (LIF(NON-ZIF)) 13P CN102 1-784-735-11 CONNECTOR, FFC 13P CN151 1-785-334-11 PIN, CONNECTOR (LIGHT ANGLE) 8P CN153 1-818-282-11 PIN, CONNECTOR (FOR PWB) 3P < DIODE > D101 6-500-335-01 DIODE MC2838-T112-1 D102 6-500-335-01 DIODE MC2838-T112-1 D105 6-501-193-01 DIODE 1SS355WTE-17 D106 6-501-193-01 DIODE 1SS355WTE-17 D107 6-501-193-01 DIODE 1SS355WTE-17 D108 1-216-295-11 SHORT CHIP 0 D109 6-501-193-01 DIODE 1SS355WTE-17 D110 8-719-053-43 LED SLR-325VCT31 (?/1) D111 6-501-193-01 DIODE 1SS355WTE-17 D112 6-501-193-01 DIODE 1SS355WTE-17 JACK OPTICAL MOTOR (TB) MOTOR (LD) PANEL www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 82 HCD-GNZ5D Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark D113 6-501-193-01 DIODE 1SS355WTE-17 D114 6-501-193-01 DIODE 1SS355WTE-17 D121 6-501-193-01 DIODE 1SS355WTE-17 < JUMPER RESISTOR > FB101 1-216-295-11 SHORT CHIP 0 FB102 1-216-295-11 SHORT CHIP 0 FB103 1-216-295-11 SHORT CHIP 0 FB104 1-216-295-11 SHORT CHIP 0 FB105 1-216-295-11 SHORT CHIP 0 < FLUORESCENT INDICATOR TUBE > FL101 1-519-811-11 INDICATOR TUBE, FLUORESCENT < IC > IC101 6-805-918-01 IC M30392MEP-A10FPU0 IC102 6-707-095-01 IC BH2210FV-E2 IC103 6-707-920-01 IC BD4828G-TR < JUMPER RESISTOR > JR101 1-216-864-11 SHORT CHIP 0 JR104 1-216-864-11 SHORT CHIP 0 JR105 1-216-864-11 SHORT CHIP 0 JR106 1-216-864-11 SHORT CHIP 0 JR107 1-216-864-11 SHORT CHIP 0 JR108 1-216-864-11 SHORT CHIP 0 JR109 1-216-864-11 SHORT CHIP 0 JR110 1-216-864-11 SHORT CHIP 0 JR111 1-216-864-11 SHORT CHIP 0 JR112 1-216-864-11 SHORT CHIP 0 JR118 1-216-864-11 SHORT CHIP 0 JR119 1-216-864-11 SHORT CHIP 0 JR120 1-216-864-11 SHORT CHIP 0 JR121 1-216-864-11 SHORT CHIP 0 JR123 1-216-864-11 SHORT CHIP 0 < TRANSISTOR > Q101 8-729-039-14 TRANSISTOR BCR133W-GEG-E6327 Q102 6-550-044-01 TRANSISTOR 2SB1689-T106 Q103 8-729-039-14 TRANSISTOR BCR133W-GEG-E6327 Q104 6-550-044-01 TRANSISTOR 2SB1689-T106 Q105 8-729-039-14 TRANSISTOR BCR133W-GEG-E6327 Q106 6-550-044-01 TRANSISTOR 2SB1689-T106 Q107 8-729-905-35 TRANSISTOR 2SC4081-R Q108 8-729-039-14 TRANSISTOR BCR133W-GEG-E6327 Q109 8-729-026-53 TRANSISTOR 2SA1576A-T106-QR Q111 8-729-039-14 TRANSISTOR BCR133W-GEG-E6327 < RESISTOR > R001 1-216-837-11 METAL CHIP 22K 5% 1/10W R002 1-216-809-11 METAL CHIP 100 5% 1/10W R003 1-216-809-11 METAL CHIP 100 5% 1/10W R004 1-216-809-11 METAL CHIP 100 5% 1/10W R005 1-216-809-11 METAL CHIP 100 5% 1/10W R006 1-216-809-11 METAL CHIP 100 5% 1/10W R007 1-216-809-11 METAL CHIP 100 5% 1/10W R008 1-216-809-11 METAL CHIP 100 5% 1/10W R009 1-216-809-11 METAL CHIP 100 5% 1/10W R010 1-216-809-11 METAL CHIP 100 5% 1/10W R011 1-216-809-11 METAL CHIP 100 5% 1/10W R012 1-216-809-11 METAL CHIP 100 5% 1/10W R013 1-216-833-11 METAL CHIP 10K 5% 1/10W R014 1-216-837-11 METAL CHIP 22K 5% 1/10W R015 1-216-841-11 METAL CHIP 47K 5% 1/10W R016 1-216-833-11 METAL CHIP 10K 5% 1/10W R017 1-216-809-11 METAL CHIP 100 5% 1/10W R018 1-216-809-11 METAL CHIP 100 5% 1/10W R019 1-216-809-11 METAL CHIP 100 5% 1/10W R020 1-216-809-11 METAL CHIP 100 5% 1/10W R021 1-216-809-11 METAL CHIP 100 5% 1/10W R022 1-216-809-11 METAL CHIP 100 5% 1/10W R023 1-216-809-11 METAL CHIP 100 5% 1/10W R024 1-216-809-11 METAL CHIP 100 5% 1/10W R025 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R026 1-216-809-11 METAL CHIP 100 5% 1/10W R027 1-216-837-11 METAL CHIP 22K 5% 1/10W R028 1-216-841-11 METAL CHIP 47K 5% 1/10W R029 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R030 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R031 1-216-833-11 METAL CHIP 10K 5% 1/10W R032 1-216-837-11 METAL CHIP 22K 5% 1/10W R033 1-216-841-11 METAL CHIP 47K 5% 1/10W R034 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R035 1-216-841-11 METAL CHIP 47K 5% 1/10W R036 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R037 1-216-833-11 METAL CHIP 10K 5% 1/10W R038 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R039 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R040 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R041 1-216-813-11 METAL CHIP 220 5% 1/10W R042 1-216-815-11 METAL CHIP 330 5% 1/10W R043 1-216-817-11 METAL CHIP 470 5% 1/10W R044 1-216-819-11 METAL CHIP 680 5% 1/10W R045 1-216-821-11 METAL CHIP 1K 5% 1/10W R046 1-216-823-11 METAL CHIP 1.5K 5% 1/10W R047 1-216-825-11 METAL CHIP 2.2K 5% 1/10W R048 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R049 1-216-833-11 METAL CHIP 10K 5% 1/10W R050 1-216-839-11 METAL CHIP 33K 5% 1/10W R051 1-216-819-11 METAL CHIP 680 5% 1/10W R052 1-216-821-11 METAL CHIP 1K 5% 1/10W R053 1-216-819-11 METAL CHIP 680 5% 1/10W R054 1-216-821-11 METAL CHIP 1K 5% 1/10W R055 1-216-819-11 METAL CHIP 680 5% 1/10W R056 1-216-821-11 METAL CHIP 1K 5% 1/10W R057 1-216-833-11 METAL CHIP 10K 5% 1/10W R058 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R059 1-216-833-11 METAL CHIP 10K 5% 1/10W R060 1-216-833-11 METAL CHIP 10K 5% 1/10W R061 1-216-813-11 METAL CHIP 220 5% 1/10W R062 1-216-815-11 METAL CHIP 330 5% 1/10W R063 1-216-817-11 METAL CHIP 470 5% 1/10W R064 1-216-823-11 METAL CHIP 1.5K 5% 1/10W R065 1-216-864-11 SHORT CHIP 0 R066 1-216-864-11 SHORT CHIP 0 R067 1-216-825-11 METAL CHIP 2.2K 5% 1/10W R068 1-216-829-11 METAL CHIP 4.7K 5% 1/10W PANEL www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 83 HCD-GNZ5D Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark R070 1-216-819-11 METAL CHIP 680 5% 1/10W R071 1-216-821-11 METAL CHIP 1K 5% 1/10W R072 1-216-817-11 METAL CHIP 470 5% 1/10W R073 1-216-833-11 METAL CHIP 10K 5% 1/10W R074 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R075 1-216-837-11 METAL CHIP 22K 5% 1/10W R076 1-216-837-11 METAL CHIP 22K 5% 1/10W R077 1-216-841-11 METAL CHIP 47K 5% 1/10W R078 1-216-837-11 METAL CHIP 22K 5% 1/10W R079 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R080 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R081 1-216-813-11 METAL CHIP 220 5% 1/10W R082 1-216-815-11 METAL CHIP 330 5% 1/10W R083 1-216-817-11 METAL CHIP 470 5% 1/10W R084 1-216-819-11 METAL CHIP 680 5% 1/10W R085 1-216-821-11 METAL CHIP 1K 5% 1/10W R086 1-216-823-11 METAL CHIP 1.5K 5% 1/10W R087 1-216-837-11 METAL CHIP 22K 5% 1/10W R088 1-216-841-11 METAL CHIP 47K 5% 1/10W R089 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R090 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R095 1-216-813-11 METAL CHIP 220 5% 1/10W R096 1-216-813-11 METAL CHIP 220 5% 1/10W R101 1-216-809-11 METAL CHIP 100 5% 1/10W R102 1-216-809-11 METAL CHIP 100 5% 1/10W R103 1-216-809-11 METAL CHIP 100 5% 1/10W R104 1-216-825-11 METAL CHIP 2.2K 5% 1/10W R105 1-216-809-11 METAL CHIP 100 5% 1/10W R106 1-216-809-11 METAL CHIP 100 5% 1/10W R107 1-216-809-11 METAL CHIP 100 5% 1/10W R108 1-216-809-11 METAL CHIP 100 5% 1/10W R109 1-216-833-11 METAL CHIP 10K 5% 1/10W R110 1-216-841-11 METAL CHIP 47K 5% 1/10W R111 1-216-851-11 METAL CHIP 330K 5% 1/10W R112 1-216-833-11 METAL CHIP 10K 5% 1/10W R113 1-216-811-11 METAL CHIP 150 5% 1/10W (E13) R113 1-216-829-11 METAL CHIP 4.7K 5% 1/10W (E3,E12,E15) R114 1-216-815-11 METAL CHIP 330 5% 1/10W (E3,E15) R114 1-216-819-11 METAL CHIP 680 5% 1/10W (E12) R114 1-216-829-11 METAL CHIP 4.7K 5% 1/10W (E13) R114 1-216-864-11 SHORT CHIP 0 (PH) R115 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R116 1-216-864-11 SHORT CHIP 0 R117 1-216-833-11 METAL CHIP 10K 5% 1/10W R118 1-216-809-11 METAL CHIP 100 5% 1/10W R119 1-216-809-11 METAL CHIP 100 5% 1/10W R120 1-216-841-11 METAL CHIP 47K 5% 1/10W R121 1-216-809-11 METAL CHIP 100 5% 1/10W R122 1-216-809-11 METAL CHIP 100 5% 1/10W R123 1-216-809-11 METAL CHIP 100 5% 1/10W R124 1-216-809-11 METAL CHIP 100 5% 1/10W R125 1-216-809-11 METAL CHIP 100 5% 1/10W R126 1-216-809-11 METAL CHIP 100 5% 1/10W R127 1-216-809-11 METAL CHIP 100 5% 1/10W R128 1-216-809-11 METAL CHIP 100 5% 1/10W R129 1-216-809-11 METAL CHIP 100 5% 1/10W R130 1-216-809-11 METAL CHIP 100 5% 1/10W R131 1-216-841-11 METAL CHIP 47K 5% 1/10W R132 1-216-841-11 METAL CHIP 47K 5% 1/10W R133 1-216-841-11 METAL CHIP 47K 5% 1/10W R134 1-216-841-11 METAL CHIP 47K 5% 1/10W R135 1-216-841-11 METAL CHIP 47K 5% 1/10W R136 1-216-841-11 METAL CHIP 47K 5% 1/10W R137 1-216-841-11 METAL CHIP 47K 5% 1/10W R138 1-216-841-11 METAL CHIP 47K 5% 1/10W R139 1-216-841-11 METAL CHIP 47K 5% 1/10W R140 1-216-841-11 METAL CHIP 47K 5% 1/10W R141 1-216-841-11 METAL CHIP 47K 5% 1/10W R142 1-216-841-11 METAL CHIP 47K 5% 1/10W R143 1-216-841-11 METAL CHIP 47K 5% 1/10W R144 1-216-841-11 METAL CHIP 47K 5% 1/10W R145 1-216-841-11 METAL CHIP 47K 5% 1/10W R146 1-216-841-11 METAL CHIP 47K 5% 1/10W R147 1-216-841-11 METAL CHIP 47K 5% 1/10W R148 1-216-841-11 METAL CHIP 47K 5% 1/10W R149 1-216-841-11 METAL CHIP 47K 5% 1/10W R150 1-216-841-11 METAL CHIP 47K 5% 1/10W R151 1-216-841-11 METAL CHIP 47K 5% 1/10W R152 1-216-864-11 SHORT CHIP 0 R153 1-216-841-11 METAL CHIP 47K 5% 1/10W R154 1-216-841-11 METAL CHIP 47K 5% 1/10W R155 1-216-841-11 METAL CHIP 47K 5% 1/10W R156 1-216-841-11 METAL CHIP 47K 5% 1/10W R157 1-216-841-11 METAL CHIP 47K 5% 1/10W R158 1-216-841-11 METAL CHIP 47K 5% 1/10W R159 1-216-841-11 METAL CHIP 47K 5% 1/10W R160 1-216-841-11 METAL CHIP 47K 5% 1/10W R161 1-216-841-11 METAL CHIP 47K 5% 1/10W R162 1-216-827-11 METAL CHIP 3.3K 5% 1/10W R163 1-216-841-11 METAL CHIP 47K 5% 1/10W R164 1-216-827-11 METAL CHIP 3.3K 5% 1/10W R165 1-216-841-11 METAL CHIP 47K 5% 1/10W R166 1-216-841-11 METAL CHIP 47K 5% 1/10W R167 1-216-841-11 METAL CHIP 47K 5% 1/10W R168 1-216-809-11 METAL CHIP 100 5% 1/10W R169 1-216-809-11 METAL CHIP 100 5% 1/10W R170 1-216-809-11 METAL CHIP 100 5% 1/10W R171 1-216-809-11 METAL CHIP 100 5% 1/10W R172 1-216-833-11 METAL CHIP 10K 5% 1/10W R173 1-216-833-11 METAL CHIP 10K 5% 1/10W R174 1-216-857-11 METAL CHIP 1M 5% 1/10W R175 1-216-864-11 SHORT CHIP 0 R177 1-216-853-11 METAL CHIP 470K 5% 1/10W R178 1-216-809-11 METAL CHIP 100 5% 1/10W R179 1-216-809-11 METAL CHIP 100 5% 1/10W R180 1-216-809-11 METAL CHIP 100 5% 1/10W R181 1-216-809-11 METAL CHIP 100 5% 1/10W R182 1-216-809-11 METAL CHIP 100 5% 1/10W R183 1-216-809-11 METAL CHIP 100 5% 1/10W R184 1-216-809-11 METAL CHIP 100 5% 1/10W R185 1-216-809-11 METAL CHIP 100 5% 1/10W R186 1-216-809-11 METAL CHIP 100 5% 1/10W PANEL www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 84 HCD-GNZ5D Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark R187 1-216-809-11 METAL CHIP 100 5% 1/10W R188 1-216-809-11 METAL CHIP 100 5% 1/10W R189 1-216-809-11 METAL CHIP 100 5% 1/10W R192 1-216-827-11 METAL CHIP 3.3K 5% 1/10W R193 1-216-827-11 METAL CHIP 3.3K 5% 1/10W R194 1-216-827-11 METAL CHIP 3.3K 5% 1/10W R195 1-216-809-11 METAL CHIP 100 5% 1/10W R197 1-216-809-11 METAL CHIP 100 5% 1/10W R198 1-216-864-11 SHORT CHIP 0 R199 1-216-821-11 METAL CHIP 1K 5% 1/10W R200 1-216-809-11 METAL CHIP 100 5% 1/10W < SWITCH > S11 1-762-875-21 SWITCH, KEYBOARD (?/1) S12 1-762-875-21 SWITCH, KEYBOARD (EQ BAND/MEMORY) S14 1-762-875-21 SWITCH, KEYBOARD (PRESET EQ) S15 1-762-875-21 SWITCH, KEYBOARD (DIRECTION) S16 1-762-875-21 SWITCH, KEYBOARD (DISC 3) S17 1-762-875-21 SWITCH, KEYBOARD (DISC 2) S18 1-762-875-21 SWITCH, KEYBOARD (DISC 1) S19 1-762-875-21 SWITCH, KEYBOARD (DISC SKIP/EX-CHANGE) S20 1-762-875-21 SWITCH, KEYBOARD (Z OPEN/CLOSE) S31 1-762-875-21 SWITCH, KEYBOARD (DISPLAY) S32 1-762-875-21 SWITCH, KEYBOARD (TUNER/BAND) S33 1-762-875-21 SWITCH, KEYBOARD (TAPE A/B) S34 1-762-875-21 SWITCH, KEYBOARD (CD SYNC) S35 1-762-875-21 SWITCH, KEYBOARD (REC PAUSE/START) S38 1-762-875-21 SWITCH, KEYBOARD ( m TUNING –) S51 1-762-875-21 SWITCH, KEYBOARD (Y) S52 1-762-875-21 SWITCH, KEYBOARD (SOUND FIELD) S53 1-762-875-21 SWITCH, KEYBOARD (X) S54 1-762-875-21 SWITCH, KEYBOARD (x) S55 1-762-875-21 SWITCH, KEYBOARD (M y TUNING +) S56 1-762-875-21 SWITCH, KEYBOARD (GROOVE) S57 1-762-875-21 SWITCH, KEYBOARD (DVD) < VIBRATOR > X101 1-795-482-11 VIBRATOR, CERAMIC (16MHz) X102 1-760-252-12 VIBRATOR, CRYSTAL (32.768kHz) ************************************************************* 1-687-132-12 SENSOR BOARD ************** < CONNECTOR > CN731 1-785-329-21 PIN, CONNECTOR (LIGHT ANGLE) 3P < IC > IC731 6-600-022-01 IC RPI-576 ************************************************************* SIRCS BOARD ************ < CAPACITOR > C148 1-162-974-11 CERAMIC CHIP 0.01uF 50V < CONNECTOR > CN143 1-816-423-11 SOCKET, CONNECTOR 3P < IC > IC104 6-600-309-01 IC RPM7240-H9 (IR) < JUMPER RESISTOR > JR102 1-216-864-11 SHORT CHIP 0 ************************************************************* STREAM BOARD ************** < DIODE > D117 8-719-085-33 LED SLI-343URCT32WST (RING ILLUMINATION) D118 8-719-085-33 LED SLI-343URCT32WST (RING ILLUMINATION) < JUMPER RESISTOR > JR113 1-216-864-11 SHORT CHIP 0 JR114 1-216-864-11 SHORT CHIP 0 JR115 1-216-864-11 SHORT CHIP 0 JR116 1-216-864-11 SHORT CHIP 0 JR117 1-216-864-11 SHORT CHIP 0 < RESISTOR > R069 1-216-833-11 METAL CHIP 10K 5% 1/10W < SWITCH > S101 1-786-289-11 SWITCH, DETECTION (l – EQ + L) < ROTARY ENCODER > S102 1-418-725-41 ENCODER, ROTARY (12 TYPE) (MASTER VOLUME) ************************************************************* SUB TRANS BOARD **************** 1-533-217-41 HOLDER, FUSE (E3,E15,PH) < CAPACITOR > C902 1-164-159-11 CERAMIC 0.1uF 50V C903 1-164-159-11 CERAMIC 0.1uF 50V < CONNECTOR > CN901 1-564-321-00 PIN, CONNECTOR (3.96mm PITCH) 2P CN902 1-785-314-11 PIN, CONNECTOR (STRAIGHT) 2P < DIODE > D901 8-719-991-33 DIODE 1SS133T-77 < COIL > L901 1-414-189-31 INDUCTOR 100uH PANEL y SENSOR SIRCS STREAM SUB TRANS www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 85 HCD-GNZ5D Ref. No. Part No. Description Remark < TRANSISTOR > Q901 8-729-119-78 TRANSISTOR 2SC2785-HFE < RESISTOR > R901 1-249-429-11 CARBON 10K 5% 1/4W R904 1-249-393-11 CARBON 10 5% 1/4W < RELAY > 0RY901 1-755-324-11 RELAY < SWITCH > 0S901 1-786-055-21 SELECTOR, VOLTAGE (VOLTAGE SELECTOR) (E3,E15,PH) ************************************************************* 1-687-669-12 SW BOARD ********** < SWITCH > S751 1-786-514-11 SWITCH, LEVER (SLIDE) (OPEN/CLOSE DET) ************************************************************* TRANS BOARD ************* 1-533-217-41 HOLDER, FUSE < CAPACITOR > C912 1-126-960-11 ELECT 1uF 20% 50V (E12,E13) C913 1-126-968-11 ELECT 100uF 20% 50V C915 1-164-159-11 CERAMIC 0.1uF 50V C918 1-128-576-11 ELECT 100uF 20% 63V < CONNECTOR > * CN914 1-564-525-11 PLUG, CONNECTOR 10P * CN915 1-564-519-11 PLUG, CONNECTOR 4P < DIODE > D911 6-500-522-11 DIODE 10EDB40-TA2B5 D912 8-719-982-19 DIODE MTZJ-30A D913 8-719-118-64 DIODE RD5.6F-T7B3 < TRANSISTOR > Q902 8-729-140-97 TRANSISTOR 2SB734-34 < RESISTOR > 0R911 1-217-637-00 FUSIBLE 1 5% 1/4W F R914 1-249-429-11 CARBON 10K 5% 1/4W R915 1-247-807-31 CARBON 100 5% 1/4W R916 1-247-807-31 CARBON 100 5% 1/4W R919 1-249-429-11 CARBON 10K 5% 1/4W ************************************************************* A-1109-328-A VIDEO BOARD, COMPLETE ********************** < CAPACITOR > C801 1-104-655-11 ELECT 470uF 20% 6.3V C802 1-162-306-11 CERAMIC 0.01uF 20% 16V C811 1-126-960-11 ELECT 1uF 20% 50V C812 1-126-916-11 ELECT 1000uF 20% 6.3V C813 1-162-282-31 CERAMIC 100PF 10% 50V C840 1-162-282-31 CERAMIC 100PF 10% 50V C841 1-162-282-31 CERAMIC 100PF 10% 50V C842 1-162-282-31 CERAMIC 100PF 10% 50V C850 1-126-942-61 ELECT 1000uF 20% 25V C851 1-164-159-11 CERAMIC 0.1uF 50V C852 1-117-245-11 ELECT 330uF 20% 6.3V C853 1-126-960-11 ELECT 1uF 20% 50V C854 1-164-159-11 CERAMIC 0.1uF 50V C856 1-117-245-11 ELECT 330uF 20% 6.3V C862 1-117-317-11 ELECT 1000uF 20% 25V C863 1-128-646-11 ELECT 1000uF 20% 6.3V C865 1-117-245-11 ELECT 330uF 20% 6.3V C866 1-117-245-11 ELECT 330uF 20% 6.3V C872 1-164-159-11 CERAMIC 0.1uF 50V C873 1-104-658-11 ELECT 100uF 20% 10V < CONNECTOR > CN801 1-779-273-11 CONNECTOR, FFC (LIF(NON-ZIF)) 5P * CN851 1-564-724-11 PIN, CONNECTOR (SMALL TYPE) 8P < DIODE > D861 8-719-210-21 DIODE 11EQS04 < GROUND TERMINAL > EP801 1-537-771-21 TERMINAL BOARD, GROUND EP851 1-537-771-21 TERMINAL BOARD, GROUND < IC > IC801 6-600-495-01 IC MM1671XNRE IC851 6-705-463-01 IC BA33BC0T IC861 8-759-474-09 IC SI-8050S-LF1101 < JACK > J801 1-794-970-11 JACK, PIN 1P (VIDEO OUT) < COIL > L801 1-410-470-11 INDUCTOR 10uH L861 1-456-513-11 INDUCTOR 150uH L862 1-414-741-11 INDUCTOR 10uH < TRANSISTOR > Q861 8-729-029-66 TRANSISTOR DTC114ESA Q870 8-729-029-66 TRANSISTOR DTC114ESA < RESISTOR > R801 1-249-429-11 CARBON 10K 5% 1/4W R811 1-247-804-11 CARBON 75 5% 1/4W R812 1-247-879-11 CARBON 100K 5% 1/4W Ref. No. Part No. Description Remark SUB TRANS SW TRANS VIDEO www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 86 HCD-GNZ5D R870 1-247-807-31 CARBON 100 5% 1/4W R871 1-249-429-11 CARBON 10K 5% 1/4W ************************************************************* MISCELLANEOUS *************** 7 1-828-956-11 WIRE (FLAT TYPE) (9 CORE) 55 1-828-977-11 WIRE (FLAT TYPE) (13 CORE) 56 1-828-971-11 WIRE (FLAT TYPE) (13 CORE) 57 1-829-041-11 WIRE (FLAT TYPE) (27 CORE) 58 1-797-246-11 DECK, MECHANISM 59 1-828-332-11 WIRE (FLAT TYPE) (13 CORE) 202 1-828-354-11 WIRE (FLAT TYPE) (17 CORE) 203 1-828-290-11 WIRE (FLAT TYPE) (5 CORE) 0254 1-777-071-23 CORD, POWER (E12,E13,PH) 0254 1-827-226-31 CORD, POWER (E3,E15) 0255 1-468-737-21 POWER, SWITCHING 352 1-776-182-11 WIRE (FLAT TYPE) (5 CORE) 421 1-828-771-51 WIRE (FLAT TYPE) (24 CORE) 0422 8-820-291-02 OPTICAL PICK-UP (KHM-310CAB/C2RP) 0F910 1-532-504-33 FUSE (4A/250V) (E3,E15,PH) 0F914 1-532-506-33 FUSE (6.3A/250V) 0F915 1-532-506-33 FUSE (6.3A/250V) 0F918 1-532-504-33 FUSE (4A/250V) 0F919 1-532-504-33 FUSE (4A/250V) FAN901 1-763-072-11 FAN, DC IC941 8-759-198-03 IC PQ09RF21J00H IC942 8-759-701-59 IC NJM78M09FA IC943 8-759-701-59 IC NJM78M09FA IC945 6-703-546-01 IC TA7804LS M741 A-1108-965-A MOTOR ASSY, TABLE (TABLE) M751 A-1108-966-A MOTOR ASSY, LOADING (LOADING) RE701 1-477-680-12 ENCODER, ROTARY (DISC TRAY ADDRESS DETECT) 0T911 1-443-792-11 TRANSFORMER, POWER TN1 1-693-671-11 TUNER (FM/AM) (TM-10E) Ref. No. Part No. Description Remark VIDEO www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 87 HCD-GNZ5D MEMO www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 88 HCD-GNZ5D REVISION HISTORY Clicking the version allows you to jump to the revised page. Also, clicking the version at the upper on the revised page allows you to jump to the next revised page. Ver. Date Description of Revision 1.0 2005. 08 New 1.1 2005. 12 DVD section electrical adjustment alteration. Addition of note on DMB11 board replacement. (SPM-05077) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com
