SERVICE MANUAL Model Name Using Similar Mechanism NEW CD CD Mechanism Type CDM74-K6BD47S Section Base Unit Name BU-K6BD47S Optical Pick-up Name KSM-213DCP TAPE Model Name Using Similar Mechanism HCD-XGR88 Section Tape Transport Mechanism Type CWM43RR23 MiNi Hi-Fi COMPONENT SYSTEM E Model HCD-GN600 Ver 1.0 2003.04 9-877-282-01 Sony Corporation 2003D0200-1 Home Audio Company C 2003.04 Published by Sony Engineering Corporation SPECIFICATIONS HCD-GN600 is the amplifier, CD player, tape deck and tuner section in MHC- GN600. – Continued on next page – Amplifier section The following are measured at AC 127V, 60 Hz (Mexican model only) The following are measured at AC 120, 220, 240V50/60 Hz (except Mexican model) DIN power output (rated) 130 + 130 watts (6 ohms at 1 kHz, DIN) Continuous RMS power output (reference) 165 + 165 watts (6 ohms at 1 kHz, 10% THD) Inputs GAME (VIDEO): 1 Vp-p, 75 ohms (phono jack) GAME (AUDIO): Voltage 250 mV, (phono jacks) impedance 47 kilohms MD/VIDEO (AUDIO) IN: voltage 450 mV/250 mV, (phono jacks) impedance 47 kilohms MIC: sensitivity 1 mV, (phone jack) impedance 10 kilohms Outputs VIDEO OUT: max. output level 1 Vp-p, (phono jacks) unbalanced, Sync. negative load impedance 75 ohms PHONES: accepts headphones of (stereo mini jack) 8 ohms or more FRONT SPEAKER: accepts impedance of 6 to 16 ohms CD player section System Compact disc and digital audio system Laser Semiconductor laser (λ=795nm) Laser Output Max. 44.6 µW* *This output is the value measured at a distance of 200 mm from the objective lens surface on the Optical Pick-up Block with 7 mm aperture. Frequency response 2 Hz – 20 kHz (±0.5 dB) Wave length 795 nm CD OPTICAL DIGITAL OUT (Square optical connector jack, rear panel) Wave length 660 nm Output Level –18 dBm Tape player section Recording system 4-track 2-channel stereo Frequency response 50 – 13,000 Hz (±3 dB), using Sony TYPE I cassette www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com HCD-GN600 2 Notes on chip component replacement • Never reuse a disconnected chip component. • Notice that the minus side of a tantalum capacitor may be dam- aged by heat. Flexible Circuit Board Repairing • Keep the temperature of the soldering iron around 270 ˚C dur- ing repairing. • Do not touch the soldering iron on the same conductor of the circuit board (within 3 times). • Be careful not to apply force on the conductor when soldering or unsoldering. CAUTION Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous ra- diation exposure. SAFETY-RELATED COMPONENT WARNING!! COMPONENTS IDENTIFIED BY MARK 0 OR DOTTED LINE WITH MARK 0 ON THE SCHEMATIC DIAGRAMS AND IN THE PARTS LIST ARE CRITICAL TO SAFE OPERATION. REPLACE THESE COMPONENTS WITH SONY PARTS WHOSE PART NUMBERS APPEAR AS SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUB- LISHED BY SONY. This appliance is classified as a CLASS 1 LASER product. The CLASS 1 LASER PRODUCT MARKING is located on the rear exterior. Tuner section FM stereo, FM/AM superheterodyne tuner FM tuner section Tuning range 87.5 – 108.0 MHz Antenna FM lead antenna Antenna terminals 75 ohm unbalanced Intermediate frequency 10.7 MHz AM tuner section Tuning range North and Latin American models: 530 – 1,710 kHz (with the interval set at 10 kHz) 531 – 1,710 kHz (with the interval set at 9 kHz) Middle Eastern models: 531 – 1,602 kHz (with the interval set at 9 kHz) Other models: 531 – 1,602 kHz (with the interval set at 9 kHz) 530 – 1,710 kHz (with the interval set at 10 kHz) Antenna AM loop antenna Antenna terminals External antenna terminal Intermediate frequency 450 kHz General Power requirements Mexican models: 127 V AC, 60 Hz Argentina models: 220 V AC, 50/60 Hz Other models: 120 V, 220 V or 230 - 240 V AC, 50/60 Hz Adjustable with voltage selector Power consumption 145 watts Dimensions (w/h/d) Approx. 280 x 360 x 386.5 mm Mass : Approx. 10.5 kg Design and specifications are subject to change without notice. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com HCD-GN600 3 TABLE OF CONTENTS 1. SERVICING NOTES ................................................ 4 2. GENERAL Location of Controls ....................................................... 5 3. DISASSEMBLY 3-1. Case ................................................................................. 8 3-2. Loading (Panel) ............................................................... 8 3-3. Front Panel Assy ............................................................. 9 3-4. Tuner Pack, Sub Trans Board ......................................... 9 3-5. CD Mechanism Deck ...................................................... 10 3-6. Game In Board, Tape Mechanism Deck......................... 10 3-7. CD Switch Board, Display Board .................................. 11 3-8. Volume Board.................................................................. 11 3-9. Subwoofer Board, Rear Panel ........................................ 12 3-10. Main Board...................................................................... 12 3-11. Power Amp Board ........................................................... 13 3-12. SW Board, Driver Board................................................. 13 3-13. CD Board, CD Block Assy ............................................. 14 3-14. Sensor Board ................................................................... 14 3-15. Motor (TB) Board ........................................................... 15 3-16. Motor (LD) Board ........................................................... 15 4. TEST MODE .............................................................. 16 5. MECHANICAL ADJUSTMENTS ....................... 20 6. ELECTRICAL ADJUSTMENTS Deck section .................................................................... 20 CD Section ...................................................................... 22 7. DIAGRAMS 7-1. Circuit Board Location ................................................... 26 7-2. Block Diagram – CD Servo Section –........................... 28 Block Diagram – Tuner/Tape Deck Section – ............... 29 Block Diagram – Main/Power Section – ....................... 30 Block Diagram – Display Section – .............................. 31 7-3. Printed Wiring Board – CD Board – ............................. 32 7-4. Schematic Diagram – CD Board – ................................ 33 7-5. Printed Wiring Board – CD Mechanism Board – ......... 34 7-6. Schematic Diagram – CD Mechanism Board – ............ 35 7-7. Printed Wiring Boards – Main Board – ......................... 36 7-8. Schematic Diagram – Main Board (1/3) – .................... 37 7-9. Schematic Diagram – Main Board (2/3) – .................... 38 7-10. Schematic Diagram – Main Board (3/3) – .................... 39 7-11. Printed Wiring Boards – Game In, CD Switch Board – ...................................... 40 7-12. Schematic Diagram – Game In, CD Switch Board – ...................................... 41 7-13. Printed Wiring Board – Display Board – ...................... 42 7-14. Schematic Diagram – Display Board – ......................... 43 7-15. Printed Wiring Board – Power Amp Board – ................ 44 7-16. Schematic Diagram – Power Amp Board –................... 45 7-17. Printed Wiring Boards – Trans Board – ........................ 46 7-18. Schematic Diagram – Trans Board – ............................. 47 7-19. IC Block Diagram ........................................................... 48 7-20. IC Pin Function Description ........................................... 49 8. EXPLODED VIEWS 8-1. Case, Rear Panel Section ................................................ 54 8-2. Front Panel Section ......................................................... 55 8-3. Chassis Section ............................................................... 56 8-4. CD Mechanism Deck Section-1 (CDM74-K6BD47S) ....................................................... 57 8-5. CD Mechanism Deck Section-2 (CDM74-K6BD47S) ....................................................... 58 9. ELECTRICAL PARTS LIST ............................... 59 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 4 HCD-GN600 SECTION 1 SERVICING NOTES NOTES ON HANDLING THE OPTICAL PICK-UP BLOCK OR BASE UNIT The laser diode in the optical pick-up block may suffer electro- static break-down because of the potential difference generated by the charged electrostatic load, etc. on clothing and the human body. During repair, pay attention to electrostatic break-down and also use the procedure in the printed matter which is included in the repair parts. The flexible board is easily damaged and should be handled with care. NOTES ON LASER DIODE EMISSION CHECK The laser beam on this model is concentrated so as to be focused on the disc reflective surface by the objective lens in the optical pick-up block. Therefore, when checking the laser diode emis- sion, observe from more than 30 cm away from the objective lens. LASER DIODE AND FOCUS SEARCH OPERATION CHECK Carry out the “S curve check” in “CD section adjustment” and check that the S curve waveforms is output three times. • MODEL IDENTIFICATION – Back Panel – MODEL PART No. E2 model 4-244-103-0[] E51 model 4-244-103-1[] Mexican model 4-244-103-2[] Argentina model 4-244-103-3[] • Abbreviation E2 : 120 V AC Area in E model E51 : Chilean and Peruvian model PART No. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 5 HCD-GN600 SECTION 2 GENERAL ALBUM +/- qg AMP MENU rd CD r; CD SYNC qj DECK A wk DECK B wd DIRECTION 9 DISC 1~3 3 DISC SKIPEX-CHANGE 4 Disc tray 6 DISPLAY ra Display 2 EDIT9 EFFECT ON/OFF rf FM MODE 8 GAME eh GAME EQ ea GAME INPUT (jacks) wj GAME MIXING ef GROOVEed IR (receptor) rs ILLUMINATION wl MD (VIDEO) ej MIC (jack) wh MIC LEVEL wg MOVIE EQ qh MUSIC EQ eg OPEN/CLOSE Z 5 P FILE wa PHONES (jack) wf PLAY MODE 7 Power illuminator e; PUSH ENTER q; REC PAUSE/START qk REPEAT 8 SURROUND w; TAPE A/B ek TUNER/BAND el TUNER MEMORY 7 VOLUME ws SYMBOLS @/1 (power) 1 hH (play) qa x (stop) qs X (pause) qd . (go backward) qf > + (go forward) qf m (rewind) qg M (fast forward) qg V/v/B/b q; A A (Eject A) es A B (Eject B) ql ALPHABETICAL ORDER A - D M - Q wk ek wl el e; ea es eg ed ef ej eh rd r; ra rs rf wf wg wh wj qs qd qf qg qh qj ql qk w; wa ws wd 0 qa 4 5 6 1 2 3 7 8 9 Main unit E - L R - Z This section is extracted from instruction manual. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 6 HCD-GN600 Remote Control 4 5 qk ql w; wa ws 1 2 3 wg wf wd qh qj qa qs qd qf 7 q; qg 8 9 6 CD ql CLEAR 7 CLOCK/TIMER SELECT 2 CLOCK/TIMER SET 3 D.SKIP 9 ENTER qd EFFECT ON/OFF qf GAME w; MD (VIDEO) q; PRESET - wd PRESET + wf PRESET EQ qj P FILE qh SURROUND qs SLEEP 1 TAPE A/B qa TUNER/BAND qk TUNING - wa TUNING + ws VOL +/- 8 SYMBOLS @/1 (power) 4 nN (play) wg X (pause) 5 x (stop) 6 .(go backward) wd > (go forward) wf m (rewind) wa M (fast forward) ws M/m/ button or . button to display next error) $$: Not used %%: Loading related error (Second figure is not used) D: Stop by the problem other than mechanical problem while closing. E: Stop by the problem other than mechanical problem while opening. C: Stop by the problem other than mechanical problem while chucking up. F: Stop by the problem other than mechanical problem while chucking down. &&: Emerging error 01: Stop while chucking up. 02: Stop while chucking up. 03: Time-out of EX-CHANGE open. 05: Time-out of EX-CHANGE close. ##: Not used 3) Display of no disc errors D*: The number of mechanical error (“00” is latest one) (Press > button or . button to display next error) $$: Error type 01: Focus error 02: GFS error 03: Setup error %%: Not used &&: 00: No disc judgment without chucking retry. 01: No disc judgment after chucking retry. ##: The state when judged as no disc 01: Stop 02: Setup 03: TOC reading 04: Access 05: Playback 06: Pause 07: Manual search (Play) 08: Manual search (Pause) [CD REPEAT 5 LIMIT OFF MODE] • The number of repeat for CD playback is 5 times when the repeat mode is “REPEAT ALL”. This mode enables CD to repeat playback for limitless times. Procedure: 1. Press ?/1 button to turn the set ON. 2. Select CD function. 3. Press x button, [REPEAT] button and [CD] button simultaneously to enter the CD repeat 5 limit off mode and the fluorescent indicator tube displays “LIMIT OFF”. 3. To release this mode, operate the cold reset. (Refer to the “MC COLD RESET”) [CD SHIP MODE (WITH MEMORY CLEAR)] • This mode moves the optical pick-up to the position durable to vibration and clears all data including preset data stored in the RAM to initial conditions. Use this mode when returning the set to the customer after repair. Procedure: 1. Press ?/1 button to turn the set ON. 2. Select CD function. 3. Press x button, [AMP MENU] button and [GAME] button simultaneously. The set will power off automatically. 4. After the “STANDBY” blinking display finish, a message “LOCK” is displayed on the fluorescent indicator tube and the CD ship mode is set. Display EMC**EDC** Display M*$$%%&&##00 Display D*$$%%&&##00 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 19 HCD-GN600 [CD SHIP MODE (WITHOUT MEMORY CLEAR)] • This mode moves the optical pick-up to the position durable to vibration. Use this mode when returning the set to the customer after repair. Procedure: 1. Press ?/1 button to turn the set ON. 2. Select CD function. 3. Press [CD] button and ?/1 button simultaneously. The set will power off automatically. 4. After the “STANDBY” blinking display finish, a message “LOCK” is displayed on the fluorescent indicator tube and the CD ship mode is set. [CD POWER MANAGE] • This mode let you switch on or off power supply to the BU during TUNER function. • When CD POWER is set to OFF, the power supply to the BU is cut off during TUNER function. It will increase the time taken to access CD when function change from TUNER to CD but it will improve tuner reception. • When CD POWER is set to ON, the power supply to the BU is not cut off during TUNER function. It will reduce the time taken to access CD when function change from TUNER to CD but it will decrease tuner reception performance. Procedure: 1. Press ?/1 button to turn the set ON. 2. Select CD function. 3. Press ?/1 button to turn the set OFF. 4. Press x button and ?/1 button simultaneously. The set will power on automatically. 5. The message “CD POWER ON” or “CD POWER OFF” will be displayed on the fluorescent indicator tube. [CD TRAY LOCK MODE] • This mode let you lock the disc trays. When this mode is activated, the disc tray will not open when Z OPEN/CLOSE button or [DISC SKIP/EX-CHANGE] button is pressed. The message “LOCKED” will be displayed in the will be displayed on the fluorescent indicator tube. Procedure: 1. Press ?/1 button to turn the set ON. 2. Select CD function. 3. Press x button and Z OPEN/CLOSE button simultaneously and hold down until “LOCKED” or “UNLOCKED” displayed on the fluorescent indicator tube (around 5 seconds). [MD/VIDEO SWITCHING] • This mode let you switch from MD to VIDEO and vice-versa. Procedure: 1. Press ?/1 button to turn the set ON. 2. Select MD function. 3. Press [MD (VIDEO)] button and ?/1 button simultaneously. The function will change to VIDEO. Press the same buttons again to change from VIDEO to MD. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 20 HCD-GN600 SECTION 5 MECHANICAL ADJUSTMENTS SECTION 6 ELECTRICAL ADJUSTMENTS Precaution 1. Clean the following parts with a denatured alcohol-moistened swab: record/playback heads pinch rollers erase head rubber belts capstan idlers 2. Demagnetize the record/playback head with a head demagnetizer. 3. Do not use a magnetized screwdriver for the adjustments. 4. After the adjustments, apply suitable locking compound to the parts adjusted. 5. The adjustments should be performed with the rated power supply voltage unless otherwise noted. Torque Measurement 3.06 N • m to 6.96 N • m 31 to 71 g • cm (0.43 – 0.98 oz • inch) 0.19 N • m to 0.58 N • m 2 to 6 g • cm (0.02 – 0.08 oz • inch) 3.06 N • m to 6.96 N • m 31 to 71 g • cm (0.43 – 0.98 oz • inch) 0.19 N • m to 0.58 N • m 2 to 6 g • cm (0.02 – 0.08 oz • inch) 6.96 N • m to 14.02 N • m 71 to 143 g • cm (0.98 – 1.99 oz • inch) 9.80 N • m 100 g or more (3.53 oz or more) 9.80 N • m 100 g or more (3.53 oz or more) Mode Torque meter CQ-102C CQ-102C CQ-102RC CQ-102RC CQ-201B CQ-403A CQ-403R Meter reading FWD FWD back tension REV REV back tension FF/REW FWD tension REV tension 0 dB=0.775 V DECK SECTION 1. Demagnetize the record/playback head with a head demagnetizer. 2. Do not use a magnetized screwdriver for the adjustments. 3. After the adjustments, apply suitable locking compound to the parts adjust. 4. The adjustments should be performed with the rated power supply voltage unless otherwise noted. 5. The adjustments should be performed in the order given in this service manual. (As a general rule, playback circuit adjustment should be completed before performing recording circuit adjustment.) 6. The adjustments should be performed for both L-CH and R- CH. 7. Switches and controls should be set as follows unless otherwise specified. • Test Tape RECORD/PLAYBACK HEAD AZIMUTH ADJUST- MENT DECK A DECK B Note: Perform this adjustments for both decks Procedure: 1. Mode: Playback Tape Signal Used for P-4-A100 10 kHz, –10 dB Azimuth Adjustment set MAIN board CN301 Pin 1 (L-CH) Pin 3 (R-CH) MAIN board CN301 Pin 2 (GND) + – level meter test tape P-4-A100 (10 kHz, –10 dB) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 21 HCD-GN600 2. Turn the adjustment screw and check output peaks. If the peaks do not match for L-CH and R-CH, turn the adjustment screw so that outputs match within 1dB of peak. 3. Mode: Playback 4. After the adjustments, apply suitable locking compound to the pats adjusted. Adjustment Location: Playback Head (Deck A). Record/Playback/Erase Head (Deck B). REC BIAS ADJUSTMENT DECK B Procedure: In the MC test mode, the “REC memory mode” is convenient for this adjustment. In the “REC memory mode” , when the REC starts the input signal FUNCTION is switched to VIDEO automatically. When the REC stops, the tape returns near to the recording start position. 1. Press MD (VIDEO) button to select VIDEO. (This step is not necessary if the above test mode has already been set) 2. Insert a tape into deck B. 3. After press [REC PAUSE/START] button, press [REC PAUSE/ START] button, then recording start. 4. Mode: Record 5. Mode: Playback 6. Confirm the playback signal recorded in step 3 becomes adjustable level as follows. If these levels are not adjustable level, adjust the RV304 (L- CH) and RV354 (R-CH) on the MAIN board to repeat steps 4 and 5. Adjustable level: Playback output of 315 Hz to playback output of 10 kHz: ±1.0 dB Adjustment Location: MAIN board Screw position L-CH peak within 1dB Output level L-CH peak R-CH peak within 1dB Screw position R-CH peak MAIN board CN301 set test tape P-4-A100 (10 kHz, –10 dB) pin 3 oscilloscope L-CH R-CH V H waveform of oscilloscope in phase 45° 90° 135° 180° good wrong pin 2 pin 1 L R attenuator set MAIN board MD/VIDEO (AUDIO) IN (J750) 1) 315 Hz 2) 10 kHz 50 mV (–23.8 dB)    600 Ω blank tape CN-123 AF OSC + – set recorded portion MAIN board CN301 Pin 2 (GND) MAIN board CN301 Pin 1 (L-CH) Pin 3 (R-CH) level meter forward reverse www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 22 HCD-GN600 CD SECTION Note: 1. CD Block is basically designed to operate without adjustment. There- fore, check each item in order given. 2. Use YEDS-18 disc (3-702-101-01) unless otherwise indicated. 3. Use an oscilloscope with more than 10MΩ impedance. 4. Clean the object lens by an applicator with neutral detergent when the signal level is low than specified value with the following checks. S-curve Check Connection: Procedure: 1. Connect an oscilloscope to test point TP4 (FE) and TP 7(DVC) on the CD board. 2. Turn the power on. 3. Put the disc (YEDS-18) in and turned power switch on again and actuate the focus search. (actuate the focus search when disc table is moving in and out) 4. Check the oscilloscope waveform (S-curve) is symmetrical between A and B. And confirm peak to peak level within 2.4 ± 1 Vp-p. S-curve waveform Note: • Try to measure several times to make sure than the ratio of A : B or B : A is more than 10 : 7. • Take sweep time as long as possible and light up the brightness to obtain best waveform. Checking Location: CD board (SIDE B) (See page 24.) – MAIN BOARD (Component Side) – REC LEVEL ADJUSTMENT REC BIAS ADJUSTMENT CN301 IC301 3 1 (R-CH) (R-CH) (L-CH) (L-CH) RV301 RV351 RV304 RV354               + – CD board TP4 (FE) TP7 (DVC) oscilloscope A B symmetry within 2.4 ± 1 Vp-p REC LEVEL ADJUSTMENT DECK B Procedure: In the MC test mode, the “REC memory mode” is convenient for this adjustment. In the “REC memory mode” , when the REC starts the input signal FUNCTION is switched to VIDEO automatically. When the REC stops, the tape returns near to the recording start position. 1. Press MD (VIDEO) button to select VIDEO. (This step is not necessary if the above test mode has already been set) 2. Insert a tape into deck B. 3. After press [REC PAUSE/START] button, press [REC PAUSE/ START] button, then recording start. 4. Mode: Record 5. Mode: Playback 6. Confirm the play back signal recorded in step 3 becomes adjustable level as follows. If these levels are not adjustable level, adjust the RV301 (L- CH) and RV351 (R-CH) on the MAIN board to repeat steps 4 and 5. Adjustable level: CN301 PB level: 47.2 to 53.0 mV (–24.3 to –23.3 dB) Adjustment Location: MAIN board set MAIN board MD/VIDEO (AUDIO) IN (J117) 315 Hz, 50 mV (–23.8 dB) blank tape CS-123 600 Ω attenuator AF OSC + – set recorded portion MAIN board CN301 Pin 2 (GND) MAIN board CN301 Pin 1 (L-CH) Pin 3 (R-CH) level meter www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 23 HCD-GN600 RFAC Level Check Connection: Procedure: 1. Connect an oscilloscope to test point TP5 (RFAC) and TP 7(DVC) on the CD board. 2. Turn the power on. 3. Put the disc (YEDS-18) in to playback the number five track. 4. Confirm that oscilloscope waveform is clear and check RFAC signal level is correct or not. Note: A clear RFAC signal waveform means that the shape “◊” can be clearly distinguished at the center of the waveform. RFAC signal waveform Checking Location: CD board (SIDE B) (See page 24.) E-F Balance Check Connection: Procedure: 1. Connect an oscilloscpe to test point TP2 (TE) and TP7 (DVC) on the CD board. 2. Turn the power on. 3. Select the function “CD”. 4. Press three buttons of [ENTER], M , and [SURRUUND MODE] simultaneously to set the CD service mode. 5. Put the disc (YEDS-18) in to playback the number five track. 6. Press the . button. The message “TRAVERSE” is displayed. (The tracking servo and the sledding servo are turned OFF) 7. Check the level B of the oscilliscope's waveform and the A (DC voltage) of the center of the Traverse waveform. Confirm the following : A/B x 100 = less than ± 22% Traverse Waveform 8. Press the . button. The message “TRAVERSE” is displayed. (The tracking servo and sledding servo are turned ON) Confirm the C (DC voltage) is almost equal to the A (DC voltage) is step 5. 9. To exit from this mode, perform as follows. 1) Move the optical pick-up to the most inside track. 2) Press three buttons of x , [CLEAR], and [DISPLAY] simultaneously. (cold reset) Notes: • Always move the optical pick-up to most inside track when exiting from this mode. Otherwise, a disc will not be unloaded. • Do not run the sled motor excessively, otherwise the gear can be chipped. Traverse Waveform Checking Location: CD board (SIDE B) (See page 24.) + – CD board TP5 (RFAC) TP7 (DVC) oscilloscope VOLT/DIV: 200 mV TIME/DIV: 500 ns level: 0.9 ± 0.4 Vp-p + – CD board TP2 (TE) TP7 (DVC) oscilloscope 0V B level: 1.0 ± 0.5 Vp-p Center of the waveform A (DC voltage) 0V Tracking servo Sled servo ON C (DC voltage) Tracking servo Sled servo OFF www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 24 HCD-GN600 Checking Location: – CD BOARD (SIDE B) – TP4 (FE) TP2 (TE) TP5 (RFAC) TP7 (DVC) IC104 IC101 IC103 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 25 HCD-GN600 SECTION 7 DIAGRAMS Note on Schematic Diagram: • All capacitors are in µF unless otherwise noted. pF: µµF 50 WV or less are not indicated except for electrolytics and tantalums. • All resistors are in Ω and 1/4 W or less unless otherwise specified. • f : internal component. • 2 : nonflammable resistor. • 5 : fusible resistor. Note on Printed Wiring Boards: • X : parts extracted from the component side. • : Pattern from the side which enables seeing. (The other layers´ Patterns are not indicated.) Caution: Pattern face side: Parts on the pattern face side seen from the (Side B) pattern face are indicated. Parts face side: Parts on the parts face side seen from the (Side A) parts face are indicated. • Indication of transistor. • C : panel designation. • A : B+ Line. • B : B– Line. • H : adjustment for repair. • Voltages and waveforms are dc with respect to ground under no-signal conditions. CD board section no mark: CD PLAY Other board section no mark: TUNER (FM/AM) ( ): CD PLAY < >: TAPE PLAY [ ]: TAPE REC • Voltages are taken with a VOM (Input impedance 10 MΩ). Voltage variations may be noted due to normal produc- tion tolerances. • Waveforms are taken with a oscilloscope. Voltage variations may be noted due to normal produc- tion tolerances. • Circled numbers refer to waveforms. • Signal path. F : TUNER (FM/AM) E : TAPE PALY (DECK A) d : TAPE PALY (DECK B) G : RECORD J : CD PALY (ANALOG OUT) c : CD PALY (DIGITAL OUT) q : MD/VIDEO (AUDIO) IN j : GAME IN (AUDIO) k : GAME IN (VIDEO) N : MIC INPUT Note: The components identified by mark 0 or dotted line with mark 0 are critical for safety. Replace only with part number specified. C B These are omitted. E Q B These are omitted. C E Q B These are omitted. C E Q www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 26 HCD-GN600 7-1. CIRCUIT BOARD LOCATION TUNER PACK SUB TRANS board POWER AMP board TRANS board DISPLAY board VOLUME board GAME IN board MOTOR (LD) board SW board SENSOR board CD board MOTOR (TB) board DRIVER board MAIN board CD SWITCH board www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com HCD-GN600 27 27 T331 5 r WAVEFORMS 1 IC501 qa XC-OUT 2 3 IC501 qd X-OUT T331 4 4 – MAIN BOARD – – CD BOARD – IC101 el FE 2 IC101 ra TE 1 IC101 t; RFAC 3 – DISPLAY BOARD – IC601 is X OUT 1 3.0Vp-p 32KHz VOL/DIV : 1V AC TIME/DIV : 10µsec VOL/DIV : 1V AC TIME/DIV : 50nsec 2.0Vp-p 16MHz 240Vp-p 13µsec VOL/DIV : 50V AC TIME/DIV : 10µsec TAPE REC only VOL/DIV : 50V AC TIME/DIV : 10µsec TAPE REC only 64Vp-p 13µsec 4MHz 2.4Vp-p VOL/DIV : 1V AC TIME/DIV : 0.2µsec VOL/DIV : 0.1V AC TIME/DIV : 1msec VOL/DIV : 0.2V AC TIME/DIV : 0.2msec VOL/DIV : 0.2V AC TIME/DIV : 0.5µsec 0.15Vp-p 0.4Vp-p 0.96Vp-p w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com HCD-GN600 28 28 7-2. BLOCK DIAGRAM – CD SERVO Section – : CD • Signal Path • R-CH is omitted due to same as L-CH : DIGITAL OUT OPTICAL PICK-UP BLOCK (KSS-213DCP) A B C D E F LD VC CD A+3.3V GND PD VR LD DRIVE FOCUS COIL TRACKING COIL Q101 RF AMP IC103 DVC 14 A 6 B 7 C 8 D 9 E 10 F 11 LD 1 PD 2 IC150 MOTOR/COIL DRIVE 18 17 12 11 M M101 SLED MOTOR M M102 SPINDLE MOTOR F+ F- T+ T- 2 20 25 27 MUTE MDP 25 SRDR 30 SFDR 29 TRDR 32 TFDR 31 FRDR 34 FFDR 33 DIGITAL SIGNAL PROC. IC101 DIGITAL SERVO 64 D OUT RFAC 50 29 RFDCI 28 RFDCO 16 FE 17 FEI 12 SW RFDC 43 FE 39 TE 41 SE 40 66 PCMD OPTICAL OUT IC201 26 RO 4 DATA R-CH CD L-CH 6 CLOK 5 XLAT 77 SQCK 8 SCLK 15 SCOR 76 SQSO 26 SSTP 2 XRST S101 LIMIT IN SW CD-DATA 35 CD-CLK 37 CD-XLAT 36 SQ-CLK 33 SCOR 19 SQ-DATA-IN 32 7 SENS SENSE 34 OUT(CD) OPTICAL SYSTEM CONTROL CD/TAPE MECHANISM CONTROL IC501 (1/4) 15 RF AC 18 TE CD +3.3V SENS SQ-DATA SQ-CLK IC104 D/A CONV, MP3 DECODER SDIO 12 3 23 LO 67 BCLK BCKIA 13 65 LRCK LRCKIA 14 71 XTAI CKI/CKO 60 72 XTAO XI 62 XO 63 X201 16.9MHz 5 MIDIO 6 MICK 7 MIACK/AD2 39 PO7 1 RESET DATA IN 6 DATA OUT 5 MP3 CLK 7 25 3 MICS/AD0 MP3 CS 1 4 MILP/AD1 MP3 LP 2 MP3 ACK 3 MP3 RESET 48 MP3 REQ 18 C-XRST 40 BU-PWM3 24 BU-PWM2 26 BU-PWM1 28 LD-ON 38 +2.5V REG 1 IC121 3 +2.5V CD A+3.3V D-SENS 41 EJECTSW CD-A-MUTE Q206, 207 BUFFER Q731 S751 (LEVER) D+3.3V 42 MUTE Q201 LMF 46 LMR 47 44 TM-R E-1 E-2 E-3 45 21 22 43 TM-F 9 7 3 4 1 2 RIN FIN 9 7 MOTOR DRIVE 4 2 4 2 MOTOR DRIVE OUT OUT OUT OUT RIN FIN MOTOR DRIVER IC712 RE701 ROTARY ENCODER MOTOR DRIVER IC701 TABL SENSOR IC731 M751 (LOADING) M M M741 (TABLE) A MAIN/POWER SECTION B DISPLAY SECTION APC DRV 22 23 + – DRV + – DRV DRV 15 16 4 14 13 6 7 + – 5 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com HCD-GN600 29 29 – TUNER/TAPE DECK Section – TAPE L-CH TEST CONNECTOR CN301 R-CH R L C MAIN/POWER SECTION TUNER L – CH E MAIN POWER SECTION REC L-CH D MAIN/POWER SECTION PB HEAD DECK-A DECK-B TC BLOCK 32 BIAS OSC Q302, 303 RIPPLE FILTER Q301 A TRIG DRIVE • SIGNAL PATH : PLAYBACK (DECK A) : PLAYBACK (DECK B) : RECORD : TUNER (FM/AM) R-CH FM/AM TUNER UNIT CN304 ANTENNA ST-L FM ANT FM ANT AM ANT AM ANT ST-R ST-MUTE STEREO TUNED ST-DOUT/MC-DIN ST-DIN/MC-DOUT ST-CLK ST-CE FM 75Ω CAP M+ BTRGM+ ATRGM+ AHALF BHALF APLAY BPLAY BSHUT ASHUT REC(FWD) REC(REV) CAPM-CTRL B-TRIG A-TRIG TC-RELAY A-HALF B-HALF A-PLAY B-PLAY B-SHUT A-SHUT A REC, FWD B REC, REV REC BIAS PB-A/B ALC REC-MUTE TC-MUTE AMS-IN AM • R-ch is omitted due to same as L-ch. 93 EQ OUT1 A B 120 ST-MUTE STEREO TUNED ST-DIN ST-DOUT ST-CLK ST-CE BIAS TRAP REC BIAS(L) 34 1 2 3 4 28 27 26 24 21 56 53 54 51 52 63 60 66 90 89 61 68 91 67 55 59 B TRIG DRIVE 58 CAP MOTOR DRIVE 57 100 85 86 97 87 65 88 13 12 11 15 14 BUFFER Q304,305 HPF R-CH PB OUT1 TAI1 REC IN1 MUTE Q306,389 AMS DETECT Q390, 398, 399 R-CH R-CH L – CH R – CH R-CH R-CH SWP1 GND SWR1 AIN1 BIN1 RV304 REC(L) LEVEL RV301 C333, L301 TC A+9V REC/PB SWITCH IC302 REC/PB HEAD ERASE HEAD A/B NORM/HIGH SPEED ALC ON/OFF REC MUTE ON/OFF MUTE ON/OFF IC303 DECK A/B SELECT PB/REC EQUALIZER AMP IC301 Q307,310 T301 Q391, 392 Q395, 396 Q393,394 SYSTEM CONTROL (CD/TAPE MECHANISM CONTROL) IC501(2/4) REC-OUT1 + L – CH R – CH EQ w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com HCD-GN600 30 30 – MAIN/POWER Section – AUDIO–DATA AUDIO–CLK 79 80 M891 (FAN) + – + – SPEAKER IMPEDANCE USE 6–16Ω L R PHONES J631 RY501 D508 D509 VL (AC) VL (AC) SYSTEM CONTROLLER IC501 (3/4) R-ch is omitted due to same as L-ch. CD L-CH A CD SECTION TAPE L-CH C TUNER L-CH E TUNER/TAPE DECK SECTION TUNER/TAPE DECK SECTION TM501 D507 D511 FAN MOTOR DRIVE Q851, 852 FAN MOTOR ON SWITCH Q518 OVER LOAD DETECT SWITCH Q510 OVER LOAD DETECT Q501, 551 M HEADPHONE MUTING Q671, 624 MUTING CONTROL SWITCH Q652 + + TH502 Q602 TH501 + D502 MUTING Q620 MUTING CONTROL SWITCH Q650, 651 STANDBY SWITCH Q503, 504, 581 R-CH D130 R-CH R-CH 18 15 17 OUT1 VOLIN1 14 22 21 TOUT1 VOLUME CONTROL SOUND CONTROL CIRCUIT INPUT SELECT SWITCH 8 + R-CH R-CH INPUT SELECT SWITCH, TONE CONTROL, ELECTRICAL VOLUME IC102 IND1 INB1 INA1 INC1 6 4 3 2 INEX1 BB B1 BB A1 RECB1 SAOUT DATA CLOCK 7 5 MIC CPU INTERFACE R-CH J117 L R VIDEO/MD (AUDIO) IN R-CH A+9V RV722 J601 J716 L R GAME INPUT REC L-CH SPEANA D TUNER/TAPE DECK SECTION F DISPLAY SECTION MIC AUDIO VIDEO OUT VIDEO J721 MIC AMP IC722 (1/2) FEED BACK SWITCH Q101 SIGNAL PATH : TUNER (FM/AM) : CD PLAY : TAPE PLAY : VIDEO/MD (AUDIO) IN : GAME INPUT (AUDIO) : GAME INPUT (VIDEO) : REC : MIC INPUT FRONT SPEAKER RELAY DRIVE Q516, 517 POWER AMP IC501 OVER CURRENT PROTECTOR IC502 MIC LEVEL MIC AMP IC722 (2/2) RELAY SWITCH Q511 83 FRONT-RELAY 77 LINE-MUTE 76 HP MUTE 50 HP DETECT 78 PROTECTOR 81 VACS IN 75 STK-MUTE TEMPERATURE DETECT SWITCH Q505, 506 19 16 14 18 11 10 8 9 12 4 3 + CT OUT 1 OCP 2 VP BIAS Q721 TEMPERATURE DETECT SWITCH Q514 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com HCD-GN600 31 31 FL601 FLUORESCENT INDICATOR TUBE 8 – 10, 12 – 22, 24 – 41, 43 – 46 6 – 1, 100 – 95, 92 – 87 P1 – 36 1G – 13, G16 – 21 64 – 66 SUPER LOW FREQUENCY (BPF0) 2 BPF, RECT IC101 BPF, RECT IC102 67 70 1 2 7 6 69 68 48 93 72 94 BPF3 BPF1 BPF2 VKK SELECTOR G15 G15 G14 G14 G1 – 13, 16 – 21 6 1 7 80 VOL 1A 79 VOL 1B ROTARY ENCODER S748 VOLUME X MAIN/POWER SECTION F CD SECTION B SPEANA P1 – 36 VF1 VF2 D610 D101 D102 -VG (-32V) X601 4MHz 83 X1 82 X0 52 – 59, 73 LED DRIVE Q602 – 604, Q1001 – 1006 D603, 605, 601 D1002, 1004, 1006 D1008, 1010, 1012 D602, 606, 604 D1001, 1003, 1005, D1007, 1009, 1011 M+9V Q606 Q601 Q605 Q707 D748 KEY2 | KEY0 S782 – 792, 779 S765 – 772, 773 S751 – 763 60 IIC DATA D+3.3V CN501 D+3.3V IIC-CLK IIC PROGRAM IIC-DATA 3 2 4 61 IIC CLK 77 RESET 30 IIC-DATA 29 IIC-CLK 41 31 9 GC-RESET TXD1 TXD1 CNVSS CNVSS MCU VCC CN502 CNVSS TXD1 TXD1 RTS1 ON BOARD PROGRAM CLK1 RXD1 RESET MCU VCC CN VSS SQ-CLK SENS SQ-DATA 74 POWER-KEY 73 DISPLAY-KEY S749 S750 DISPLAY 39 STBY-LED 4 SIRCS X502 16MHz 15 X-IN 13 X-OUT X501 32.768kHz 10 XC-IN 11 XC-OUT 23 CD-POWER SYSTEM CONTROLLER IC501 (4/4) 27 STBY-RELAY 12 RESET 20 AC-CUT B+ SWITCH Q901, 902 RECT D901 +3.3V REGULATOR IC904 M +9V M +7V A +9V TC +9V D913 – 915 D502 D504 D501 D503 +3.9V REGULATOR IC903 +3.9V REGULATOR IC971 D +3.9V +9V REGULATOR IC902 +9V REGULATOR IC901 CD D+3.3V CD A+3.3V LEVEL DETECT IC601 D505 RECT D909 – 912 RECT D972 – 975 LED DRIVE Q748 T972 SUB POWER TRANSFORMER RECT D541 RECT D543 +VL VL(AC) VL(AC) F974 VL VL VH VH VP VF VF AC3 AC4 AC4 AC3 GND F975 F976 F977 F978 R941 –VL +VH –VH – 33V REGULATOR Q903 POWER ON/OFF RELAY DRIVE Q971 – VG (-32V) D977 RECT VF1 VF2 RY971 AC IN T910 MAIN POWER TRANSFORMER RESET SWITCH Q601 REMOTE CONTROL RECEIVER IC603 TO FLUORESCENT INDICATOR TUBE FL601 MCU VCC VREF EVER +3.9V S901 S901 120V | 220V | 230 – 240V DISPLAY CONTROL KEY CONTROL IC601 BUFFER Q807, 808 D103 D104 BAFFER, RECT Q100, D105 71 ALL_BAND 3 2 6 9 7 5 8 R952 VOLTAGE SELECT – DISPLAY Section – w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com HCD-GN600 32 32 7-3. PRINTED WIRING BOARD – CD Board – • See page 26 for Circuit Boards Location. C150 C273 C260 C206 C292 C256 FB104 C255 C274 C250 R279 C263 R271 FB102 C269 C259 C262 C261 C265 FB107 C131 R151 C108 R215 R152 C224 Q101 C109 C202 R156 C132 C230 C117 R214 C222 FB291 C264 C158 C215 C118 C223 C216 R201 R276 C119 R202 C151 R203 R219 IC121 C226 C133 C113 C276 R123 R122 C114 FB103 C231 C229 C115 C111 R277 R280 C279 C275 1 2 3 E 11 (11) 1-686-782- CD BOARD (SIDE A) FB106 C249 R212 R254 CN101 R249 R259 R101 R255 R257 C271 R272 C266 R275 C257 C270 R251 R250 R216 C203 C253 C252 C267 R266 R265 C251 C268 R260 C227 X201 R204 R102 C209 R104 R126 R207 R118 C212 C211 R232 R153 R132 R252 R125 C102 R114 R103 R218 R117 R113 R105 IC150 C101 C254 R131 R155 IC103 C110 C103 IC101 IC104 C152 R133 R111 R206 R231 R205 C104 C258 C208 FB101 C116 C107 R213 R230 R220 R120 C213 R253 C205 CN102 L101 R233 CD BOARD (SIDE B) 11 (11) 1-686-782- OPTICAL PICK-UP BLOCK (KSS–213DCP) A MAIN BOARD (Page 36) 1 14 28 15 41 40 21 61 80 60 20 1 1 16 48 64 49 17 32 33 M102 SPINDLE MOTOR M101 SLED MOTOR M M S101 (LIMIT) 16 30 15 1 TP7(DVD) TP5(RFAC) TP2(TE) TP4(FE) 2 3 4 5 6 7 8 A 1 B C D E IC101 B-6 IC103 C-6 IC104 C-7 IC121 D-2 IC150 B-5 Q101 D-3 • Semiconductor Location Ref. No. Location w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com HCD-GN600 33 33 7-4. SCHEMATIC DIAGRAM – CD Board – • See page 49 for Pin Function Description. R218 R205 R201 R103 R204 R202 C205 R206 R203 R104 X201 R105 R122 TP24 TP23 C104 TP22 TP21 TP2 TP3 TP4 TP9 R216 R215 R102 CN102 R118 R214 R250 R251 C260 C150 C158 TP1 R207 C223 C206 R252 TP25 TP26 TP27 TP28 TP5 TP6 TP7 TP8 C152 R220 R272 R271 R275 R257 R255 C256 C266 C264 R279 IC101 C103 C101 C202 TP16 TP13 TP12 TP17 C222 R113 R120 C151 R151 R152 TP10 TP11 TP14 TP18 TP19 TP20 TP15 R260 C273 C274 R259 R276 R213 R212 R254 R249 C269 C263 C249 R156 CN101 R123 R117 R111 R114 R253 C111 C115 R126 R277 R280 R231 R232 R233 R133 R132 R131 FB106 IC104 S101 LD PD FB291 0µH FB104 FB101 FB103 FB107 68µH L101 R125 R153 R155 C110 R219 C212 C211 R101 C250 C292 C255 C257 C270 C259 FB102 0µH 0µH 0µH C271 C258 C254 C253 R265 C267 C268 R266 C265 C262 C261 C251 C252 C227 C203 C229 C279 C275 C231 C208 C116 C117 C107 C102 C108 C131 C132 C133 C216 C215 C209 M101 M102 R230 C224 C230 C226 C213 C113 Q101 C114 C118 C276 C119 C109 IC150 IC121 IC103 1k 1k 33k 100k 2.2k 10k 0.1 F 2.2k 100k 10k 16.9M 1k 100k 3300p TE SE FE IOP 1M 0 10k 16P 10k 0 220 220 220 4V 100 10V 0.0022 B 1M 47 4V 47 4V 1M RFAC RFDC DVC MGND 0.1 F 1k 1k 10k 10k 100 100 0.1 0.1 F 47 4V 100 CXD3068Q 470p CH 470p CH 0.1 F C D E F 0.1 F 3.9k 120k 0.1 F 10k 220k VC VCC A AGND LD PD B 1k 220p B 10000p 100 100 470 470 100k 470 10 10V 10 10V 0.01 0 31P 3.3 120k 150k 390k 680 100 4V 220 4V 18k 0 0 100 100 100 2.2k 330k 68k CXD9717R-008 (LIMIT) 18k 0 0 0.1 1k 0.0022 0.1 0 0.1 1 0.1 0.33 220p 0.047 10000p 22p 22p 0.1 220 0.0022 0.0022 220 47 4V 47 4V 47 4V 0.1 0.1 0.1 0.001 0.1 1000 6.3V 220 4V 100 4V 0.1 0.1 0.1 22p 0.1 0.1 0.068 0.022 2.2 0.01 0.47 100p 220 0.1 0.1 47 4V 3300p 100 4V 2SB970 MUTE 0.001 1 100 4V 1 0.1 BA5947FP BA25BCOFP +2.5V REG CXA2647 FD+ FD- TD- TD+ SQSO DATA XLAT CLOK SENS XRST SCOR SQCK SD+ SD- SP+ SP- SP- SP+ FD- FD+ SD+ SD- TD- TD+ FFDR FRDR PWM1 PWM2 PWM3 RFSW MDP SFDR SRDR TFDR TRDR FFDR FRDR MDP SFDR SRDR TFDR TRDR LRCK ADATA BCLK XCKO SDA/MIDIO SCL/MICK SDA/MIDIO PWM1 PWM2 PWM3 RFSW SQSO XRST DATA XLAT CLOK SENS SQCK SCOR MP3RST XRST MP3REQ SCL/MICK AMUTE/MIACK AMUTE/MIACK MP3RST MICS MILP MICS MILP MP3REQ XCKO ADATA BCLK LRCK MOTOR DRIVER DIGITAL SIGNAL PROCESSOR, DIGITAL SERVO, D/A CONV. MP3 DECODER MOTOR MOTOR SLED SPINDLE COIL TRACKING COIL FOCUS RF AMP 0µH 0µH 0µH w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com HCD-GN600 34 34 Ref. No. Location D701 D-6 D711 D-7 IC701 F-6 IC712 F-7 IC731 E-11 Q731 C-9 • Semiconductor Location 7-5. PRINTED WIRING BOARDS — CD MECHANISM Board — • Refer to page 26 for Circuit Boards Location. 1 A B C D E F G H 2 3 4 5 6 7 8 9 10 11 12 13 14 15 CN751 S751 IC731 CN731 CN741 CN742 C715 C731 C735 C736 R701 R711 R731 R721 R722 R723 R735 R732 R733 R734 D701 D711 Q731 C751 IC712 IC701 CN704 C737 R713 R712 C741 R702 JW702 JW703 JW704 JW705 JW706 JW707 JW708 JW711 CN703 CN702 CN705 R751 C752 CN701 JW712 JW701 JW709 JW710 JW713 JW714 CN721 MAIN BOARD (Page 36) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com HCD-GN600 35 35 7-6. SCHEMATIC DIAGRAM – CD MECHANISM Board – R701 D701 R712 R711 R721 C735 C736 R722 C737 R723 R733 R734 R735 C741 CN731 CN741 CN742 CN702 CN703 CN751 M751 CN704 CN721 C751 R751 C752 CN705 CN751 R732 R731 M741 CN701 IC731 E-1 E-2 E-3 Q731 D711 R713 C731 C715 S751 R702 470 MTZJ-T-77-5.1B 100 1k 4.7k 0.1 0.1 4.7k 0.1 4.7k 1k 22k 100 0.01 3P 3P 5P 5P 4P 4P (LD) 2P 2P 0.01 4.7k 0.1 2P 2P 4.7k 100 (TBL) 12P RPI-576 TABLE SENSOR DTC114ESA TBL ADDRES SENS SWITCH MTZJ-T-77-3.6B 22k 10 50V 100 16V (LEVER SW) 100 VREF OUT2 RNF OUT1 VM VCC FIN GND RIN IC701 BA6956AN LD MOTOR DRIVER VREF OUT2 RNF OUT1 VM VCC FIN GND RIN BA6956AN DRIVER IC712 TBL MOTOR RE701 ROTARY ENCODER w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com HCD-GN600 36 36 7-7. PRINTED WIRING BOARDS – MAIN Boards – • See page 26 for Circuit Boards Location. Q101 D-9 Q151 E-9 Q201 D-7 Q206 D-7 Q207 D-8 Q251 D-8 Q301 I-5 Q302 I-5 Q303 I-5 Q304 I-4 Q305 I-4 Q306 F-3 Q307 I-5 Q310 I-5 Q389 F-3 Q390 F-5 Q391 E-4 Q392 E-3 Q393 E-5 Q394 F-5 Q395 F-5 Q396 F-5 Q398 F-5 Q399 F-5 Q601 B-5 Q602 D-3 Q620 F-11 Q621 I-2 Q650 F-11 Q651 F-11 Q652 J-2 Q670 F-11 Q671 I-2 Q851 G-11 Q852 G-11 Q901 D-9 Q902 D-8 Q903 H-7 Ref. No. Location Ref. No. Location D130 F-9 D392 E-4 D393 F-4 D394 F-5 D501 B-2 D502 B-2 D503 B-2 D504 B-2 D505 B-5 D508 B-2 D509 B-2 D601 B-5 D602 B-6 D603 C-5 D901 I-7 D909 H-7 D910 H-7 D911 H-7 D912 H-7 D913 G-7 D914 G-7 D915 G-7 D917 D-6 D941 H-6 IC102 E-10 IC201 B-12 IC301 G-4 IC302 I-4 IC303 F-4 IC501 C-4 IC502 J-9 IC601 C-6 IC901 H-8 IC902 H-8 IC903 H-7 IC904 C-9 • Semiconductor Location IC201 IC201 CN502 IC901 IC902 IC903 JW144 C102 C307 JW197 CN501 X501 X502 C516 C621 C598 JW198 JW154 JW296 C390 C396 C397 C365 C603 JW013 JW448 C315 JW222 C562 JW090 JW072 C602 C601 JW011 JW142 JW070 JW048 JW141 C905 C269 C904 C671 R624 R674 C351 C219 JW206 C651 JW414 JW317 C391 JW201 J716 JW200 JW207 JW275 C316 JW213 C332 JW203 JW209 JW204 C309 C306 C304 JW150 C353 C305 C310 C359 C308 C355 C354 C301 JW199 JW151 JW145 C385 C150 C167 C117 C101 C103 C104 C105 C106 C107 C108 C109 C111 C112 C113 C114 C335 L201 CN702 JW180 C331 JW146 JW179 JW202 C902 C901 C152 C153 C155 C156 C157 C158 C159 C161 C162 C163 CN851 M891 FAN DC C911 C917 C908 C909 C913 C914 C919 C921 C920 JW334 Q903 JW020 IC302 NO303 NO302 CN301 JW096 JW089 JW088 JW002 JW001 JW071 JW078 JW073 C336 L302 T301 C381 JW399 Q303 JW214 C341 JW380 R343 R344 C382 C340 C338 Q302 C337 C339 JW210 RV304 RV351 L301 L351 C356 RV301 CN902 JW034 JW057 JW061 JW038 JW012 JW079 C303 JW087 JW208 JW023 JW021 JW187 CN901 JW298 JW105 JW196 JW221 JW280 JW140 JW165 C154 JW059 JW166 JW169 JW167 JW168 JW188 C116 C121 C122 C130 C131 JW307 C852 Q851 Q852 JW295 JW058 JW279 JW294 JW211 JW313 JW256 JW147 C670 RV354 C620 JW051 JW274 JW278 JW333 JW308 JW281 JW322 CN402 JW323 C110 JW022 JW106 C160 JW170 JW174 JW019 JW228 C906 JW259 JW258 JW297 JW060 JW062 JW293 JW003 C311 C361 JW138 JW149 C312 JW324 D901 IC904 JW163 JW171 C201 J117 C140 Q393 Q396 JW052 JW410 JW050 C207 CLP4 JW035 JW164 EPT901 NO711 JW261 JW303 JW304 JW305 JW306 JW215 JW216 JW217 NO903 JW276 R853 JW330 CLP303 JW361 JW362 JW363 CLP302 JW901 JW337 Q391 JW335 JW336 JW036 JW045 JW046 JW043 JW044 JW042 JW041 JW040 JW365 JW033 C650 D909 D910 D912 D911 D913 D914 D915 JW017 JW030 JW029 JW028 JW027 JW074 JW047 JW004 JW005 JW006 JW329 JW328 JW175 JW025 JW161 JW160 JW119 JW081 JW075 JW107 JW316 JW108 JW109 JW110 JW193 JW194 JW226 JW234 JW252 JW253 JW230 JW239 JW240 JW241 JW242 JW257 JW254 JW255 JW851 JW250 JW251 JW229 JW270 JW271 JW267 JW049 JW912 NO781 CN304 JW338 JW287 JW321 JW024 JW099 JW095 JW134 JW136 JW026 JW137 JW429 JW342 JW343 JW344 JW014 JW121 JW284 NO901 JW264 JW097 JW192 JW381 JW191 JW190 JW189 JW195 JW248 JW341 JW320 JW139 JW172 JW173 JWH001 JW277 JW716 JW292 JW291 NO202 Q901 JW349 JW345 JW421 JW312 JW309 JW310 JW311 JW419 JW423 JW424 JW299 JW348 JW352 JW353 JW418 JW431 JW432 JW433 JW434 JW351 JW288 JW286 JW283 JW354 JW355 C922 JW302 JW425 C923 JW268 JW428 JW094 JW093 JW092 JW098 JW100 JW397 JW181 JW116 JW117 JW115 JW112 JW113 JW111 JW385 JW366 JW382 JW332 JW331 JW358 JW407 JW412 JW408 JW120 JW398 JW400 JW401 JW402 JW403 JW404 JW405 JW396 JW395 JW390 JW389 JW388 JW386 JW391 JW183 JW185 JW416 JW406 JW053 JW367 JW411 JW413 JW384 JW103 JW184 JW438 JW430 JW436 JW347 JW420 JW360 JW427 JW236 JW237 JW238 JW266 JW437 JW114 JW289 JW037 JW232 JW233 JW235 JW249 JW260 JW220 JW205 JW056 JW076 JW018 JW225 JW186 JW346 JW350 JW068 C209 C903 JW245 JW247 JW246 JW243 JW265 JW244 CN201 JW435 JW356 JW357 JW359 JW387 JW364 JW148 NO777 C342 C398 JR138 R140 R401 R501 C502 R502 R402 C503 R503 R504 IC303 R505 R506 R507 R509 R511 C510 C511 C512 R513 C416 FB516 R517 R419 R519 R420 R522 C498 R427 R429 R430 R532 R432 IC102 C432 C433 R433 R365 Q389 R314 R334 R395 R315 R397 R307 Q399 R396 R355 21 20 40 1 11 10 30 31 C399 R302 R398 R434 R535 R536 R537 R538 C434 R600 R540 R541 R442 R443 R444 R445 R446 R447 R448 R450 R549 R550 R542 R543 R544 R545 Q392 R394 Q394 Q395 R392 R330 D392 D393 D394 R597 R594 R593 R493 R492 R592 R591 R590 R529 R589 R581 R583 R584 R585 R586 R587 R588 R580 R579 R578 R477 R577 R576 R575 R574 R474 R473 R573 R567 R566 C564 R560 R561 R603 C427 R521 R604 D603 Q601 R601 R602 D505 D601 D602 R373 R399 R364 R360 R361 Q398 R378 R377 R376 R375 R374 R369 R368 R367 JR006 C334 C210 R304 FB204 FB286 C206 C286 C200 FB117 IC301 R676 Q621 Q671 R656 R625 R675 FB167 R168 R118 R117 R167 R255 R226 R228 FB284 R205 Q201 Q251 R204 R254 Q206 R286 R284 R285 R329 R224 R305 C321 R303 C395 R312 JR390 R306 C364 R310 R308 R309 R387 R354 R352 C326 R351 R626 C376 R150 R104 R101 R102 R103 R316 R121 R122 R154 R151 R152 R153 R156 R155 Q151 C912 C910 C915 Q902 R901 R902 R903 C918 3 1 R654 R655 Q652 R653 D941 R904 R313 R905 R906 C384 R530 C333 C383 R379 R388 R342 R345 R393 R328 Q305 JR104 Q310 R421 R422 D501 D502 D503 D504 R362 D508 D509 IC502 R370 R106 R105 Q101 R132 R131 R130 R133 R390 Q670 R353 R134 C851 R851 E E E E E E R852 R854 R327 Q602 C596 R670 R671 R672 R620 R621 R622 Q620 R623 R673 R650 Q650 Q651 R652 R333 Q306 JR013 JR001 Q390 R301 R332 IC501 C115 C211 R347 R382 R366 R523 C314 R651 Q307 R346 R317 Q304 C371 Q301 R320 D OTU 3.3V GND FB562 JR011 R391 R371 R478 R563 R372 C387 C386 JR017 JR018 R363 JR022 R112 R110 R495 JR007 R380 JR045 R565 R568 R518 R539 JR009 JR130 D130 JR103 R908 D917 JR118 JR012 R913 C924 JR003 JR008 JR005 JR015 IC601 Q207 FB203 FB202 FB205 FB201 JR016 JR26 R141 R142 C656 R157 R107 R431 JR24 C132 1 4 5 8 9 1 1 8 1 7 1 3 1 21 42 22 1 30 31 2 1 12 5 1 10 1 4 1 8 1 4 1 1 2 3 1 3 1 3 1 1 1 13 6 6 3 4 L MD/VIDEO(AUDIO) IN R L R C GAME IN BOARD (Page 40) (CHASSIS) VIDEO OUT CD DIGITAL OUT (FOR CHECK) (FOR CHECK) B A CD BOARD (Page 32) DRIVER BOARD (Page 34) TUNER PACK E POWER AMP BOARD (Page 44) D POWER AMP BOARD (Page 44) H F TRANS BOARD (Page 48) SUB TRANS BOARD (Page 48) J GAME IN BOARD (Page 40) I DISPLAY BOARD (Page 42) TAPE A HEAD TAPE B HEAD TAPE MECHANISM DECK E E E E E E E E E 1 3 E E E E E E E E E E E E E E E E E E E E E E E MAIN BOARD 11 (11) 1-686-933- 31 30 80 81 50 51 1 100 R206R256 2 3 4 5 6 7 8 9 10 11 12 13 A 1 B C D E F G H J I K w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com HCD-GN600 37 37 7-8. SCHEMATIC DIAGRAM – MAIN Board (1/3) – • See page 51 for Pin Function Description. D501 D502 D503 D504 D505 D603 Q302 Q391 Q396 Q393 D508 D392 D393 D394 D602 D601 NO302 NO303 TP318 TP325 TP320 TP309 TP311 TP338 TP432 C304 C305 C306 C307 C310 C311 C321 C326 C333 C341 C342 C354 C355 C356 C361 C371 C376 C383 C385 C427 C432 C433 C434 C498 C502 C503 C510 C511 C516 C598 C601 C602 C603 CN301 CN501 L301 L302 100µH L351 R302 R303 R304 R305 R307 R308 R309 R310 R312 R316 R317 R320 R329 R330 R332 R342 R345 R346 R347 R351 R352 R353 R354 R355 R360 R361 R363 R364 R366 R367 R368 R369 R370 R371 R372 R373 R374 R375 R376 R377 R378 R379 R380 R382 R391 R392 R393 R399 R401 R402 R420 R421 R422 R427 R432 R433 R434 R442 R443 R444 R445 R446 R447 R450 R473 R477 R478 R503 R504 R517 R518 R521 R522 R523 R532 R535 R536 R537 R538 R539 R540 R541 R542 R543 R544 R545 R549 R550 R560 R561 R565 R566 R567 R568 R573 R574 R575 R576 R577 R578 R579 R580 R581 R583 R584 R585 R586 R587 R588 R589 R590 R591 R597 R600 R601 R602 R603 R604 RV304 X501 C314 C364 C386 C387 R328 CN502 CN304 IC302 NO202 R448 R505 R506 R507 R501 R502 R431 Q395 Q394 Q392 R594 R592 R495 R430 R429 R228 R529 R530 R419 R519 R226 R224 FB516 C337 C381 C382 C331 JR017 JR008 C332 Q305 C308 R306 C211 C512 R513 R511 R509 C335 C340 C339 C384 C334 C336 R343 C596 C416 X502 Q601 IC601 IC501 Q304 Q303 RV354 T301 Q310 Q307 Q301 C359 C309 C312 RV301 RV351 C303 C301 R301 C351 C353 IC301 C564 C562 FB562 0µH JR015 R474 R344 JR018 C338 R492 R493 R593 1SS355 1SS355 1SS355 1SS355 1SS355 1SS355 2SC2001 2SB1116 2SB1116 2SB1068 1SS355 1SS355 1SS355 1SS355 1SS355 1SS355 WIRE MT WIRE MT 10 50V 1 50V 2.2 50V 10 50V 10 50V 10 50V 390p 390p 330p 10 50V 47 16V 10 50V 1 50V 2.2 50V 10 50V 390p 390p 330p 10 50V 47p 47p 47p 47p 0.1 25V 0.022 0.022 22p 0µH 15p 1000 6.3V 10 50V 10 50V 0.1 50V MF 0.1 50V MF 3P MOLEX 4P 27mH 27mH 4.7k 10k 2.2k 47k 1M 100 4.7k 100 100 10k 10k 2.2k 10k 22k 8.2k 2.2k 18k 18k 5.6k 3.3k 4.7k 10k 2.2k 47k 680 2.2k 2.2k 680 680 10k 10k 10k 2.2k 3.3k 2.2k 2.2k 10k 10k 10k 10k 10k 10k 22k 8.2k 3.3k 2.2k 4.7k 3.3k 10k 10k 4.7k 10k 10k 100 100 100 470 100 100 100 100 100 100 100 100 10k 10k 100 100 10k 100 100 100 10k 47k 470 100 470 100 100 100 100 10k 10k 10k 10k 10k 10k 100 100 100 100 100 100 10k 10k 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 220 4.7k 47k 47k 220k 32.768K 0.0022 0.0022 0.0047 0.0047 3.3k 10P 13P BA3126N 12P AMP-L 470 470 470 470 1k 1k 100k DTC114EKA DTC114EKA DTC114EKA 1k 4.7k 10k 100 100 68k 10k 10k 100 10k 150k 2.7k 0.015 0.01 120p 0.01 120p DTC114EKA 470 16V 22k 0.022 0.1 0 330k 10k 0.01 100V 0.018 0.0068 27p 27p 2.2 50V 5.6 1/4W 0.1 0.1 16M 2SC1623 RESET SWITCH M62703ML LEVEL DETECT M30622MGN-B09FP DTA124EKA 2SC2001 220k BIAS TRANS DTC114EKA SWITCH 2SA812 SWITCH 2SC3624 RIPPLE FILTER 47 16V 47 16V 10 50V 47k 47k 0.1 0.01 3.3k 0.01 0.1 HA12237 0.01 100 10V 100 5.6 1/4W 0.0068 1k 4.7k 1k A-TRG CAMP CONT B-TRG D+3.3V EVER+3.3V M+9V EVER+4V STBY RLY GND D+3.9V D3.3V B1 B2 B3 TC-PB-R REC-OUT-R TC-PB-L REC-OUT-L CD EQ OUT1 EQ OUT2 D+3.3V MUTE A+9V AMS-IN 53 58 55 59 52 51 54 55 90 89 91 56 89 47 45 37 35 34 33 32 54 53 52 51 57 58 56 29 30 4 36 31P 31P 34P 34P 33P 33P 32P 32P 9P 12P 9P 12P 43 44 46 67 90 91 61 60 23 25 38 40 41 42 49 50 59 66 75 78 79 80 57 60 61 67 66 81 83 84 73 74 77 76 24 26 28 22 21 1 2 3 5 7 48 68 68 18 85 86 87 88 97 100 47 46 45 44 21 22 43 41 42 19 65 39 94 (FOR CHECK) (FOR CHECK) TAPE MECHANISM DECK TAPE A HEAD HEAD TAPE B SYSTEM CONTROL DRIVE B TRIG DRIVE DRIVE Q391,392 A TRIG Q393,394 CAP MOTOR Q395,396 BUFFER BUFFER REC BIAS (L) REC BIAS (R) (FOR ADJUSTMENT) REC LEVEL (L) REC LEVEL (R) DECK A/B SELECT PB/REC EQUALIZER AMP w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com HCD-GN600 38 38 7-9. SCHEMATIC DIAGRAM – MAIN Board (2/3) – Q151 D130 NO781 C101 C102 C103 C104 C114 C116 C130 C131 C150 C152 C153 C154 C155 C620 C650 C670 CN702 FB117 FB167 R101 R102 R104 R105 R106 R110 R112 R118 R131 R132 R133 R150 R151 R152 R154 R155 R156 R168 R620 R621 R622 R623 R625 R650 R651 R652 R653 R654 R655 R656 R670 R671 R672 R673 R675 J117 C105 C109 C111 C159 C161 R134 R121 R122 R107 R157 R141 R142 Q652 Q650 Q651 R103 C110 R153 C160 R140 C140 C206 C210 Q399 C269 C219 R204 R313 R314 C399 C398 C397 C395 IC303(2/2) C391 Q398 Q390 R333 C316 L201 IC201 R205 R255 R256 R206 C286 C209 C207 J716 C396 R395 R394 C390 R398 R397 R327 R396 R390 IC303(1/2) R388 R387 NO711 R362 R334 CN201 C201 FB201 FB286 FB203 FB202 FB204 FB205 FB284 R285 R286 C108 C107 C106 C121 C122 C163 C162 JR130 C158 C157 C156 JR005 JR103 C651 JR016 JR009 C315 C365 R315 R365 JR390 R254 C200 Q251 Q201 C167 C117 JR118 R167 R117 R130 JR022 C112 C113 R284 R676 R626 Q671 Q621 D509 Q206 Q207 Q306 Q389 Q620 Q670 Q101 JR24 R674 R624 C621 C671 JR003 IC102 C115 C656 JR26 C132 2SC1623 1SS355 8P 100 16V 10 50V 10 50V 10 50V 10 50V 100 16V 10 50V 0.47 50V 10 50V 10 50V 10 50V 10 50V 10 50V 4.7 50V 1 50V BP 4.7 50V 11P FFC-R 0 0 2.2k 10k 1k 47k 10k 0 0 1k 2.2k 1M 100k 2.2k 2.2k 10k 1k 47k 10k 1k 10k 1k 47k 10k 1k 15k 470k 68k 1k 100k 100k 10k 10k 1k 47k 10k 1k 2P 10 50V 1 50V 10 50V 1 50V 10 50V 2.4k 1k 1k 100 100 100 100 DTA124EKA DTA124EKA DTC114EKA 620 0.01 620 0.01 10k 0.068 0.1 0.1 2SC3624A 10 50V 10 50V 10k 1k 1k 0.01 0.01 10 50V 22p NJM4565M(TE2) 100 16V DTC114EKA DTC114EKA 2.2k 1 50V JW TOTX141 1K 1K 33k 33k 0.47 3300 10V 1000 6.3V 1P 22 50V 4.7k 10k 470 10V 2.2M 15k 15k 10k 10k NJM4565M(TE2) 22k 10k 10k 100k 31P 100 10V 0µH 0 0 0 0 0 0 22k 22k 0.033 0.022 0.022 220p 220p 0.33 0.22 0.033 0.022 0.022 47 50V BP 1 50V 1 50V 10k 10k 0 10k 0.1 2SC3661 CD MUTE 2SC3661 CD MUTE 2.2 50V 2.2 50V 100k 100k 2.2k 0.22 0.33 470k 56 56 2SC3661 HEADPHONE MUTE 2SC3661 HEADPHONE MUTE 1SS355 DTC114EKA-T146 DTA124EKA-T146 DTC114EKA MUTE DTC114EKA MUTE 2SC3661 MUTING 2SC3661 MUTING 2SC1623 FEED BACK SWITCH 680 2W 0µH 680 2W 4.7 100V BP 4.7 100V BP M61529FP-D60G 0.1 0.47 0.1 R-OUT B2 TC-PB-R REC-OUT-R TC-PB-L REC-OUT-L L-IN R-IN HP-R HP-L B1 SPEANA A+9V DBFB F/B GND CD CD-A+3.3V CD-D+3.3V M+7V EQ OUT1 EQ OUT2 D+3.3V MUTE AMS-IN D+3.9V 77 80 100 50 85 86 87 88 97 65 76 7 3 5 48 18 24 26 28 38 32 33 35 37 34 19 1 2 36 40 25 79 OUT R L CD OPTICAL BUFFER BUFFER HPF IC303 AMS DETECT Q390,398,399 MUTING CONTROL SWITCH Q650-652 INPUT SELECT SWITCH TONE CONTROL ELECTRICAL VOLUME w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com HCD-GN600 39 39 7-10. SCHEMATIC DIAGRAM – MAIN (3/3) Boards – D901 Q852 NO903 C901 C903 C911 C913 C914 C917 C921 CN402 CN851 CN901 CN902 EPT901 R851 R852 R901 R902 R903 R904 R905 R906 D941 NO901 R908 R853 C922 D909 D912 D910 D911 D913 D914 D915 C919 C918 C915 JW901 C912 C910 JW851 C851 C906 C924 JW912 R913 R854 C909 C908 C920 C905 C904 JW907 IC502 Q903 Q851 Q902 Q901 IC904 IC903 IC902 IC901 R563 Q602 D917 C923 C902 D3SBA20-4101 2SC2603 7P 3300 25V 2200 16V 470 16V 470 16V 470 16V 470 10V 100 50V 19P FFC-R 3P 6P B-TO-B 13P B-TO-B GND PLATE 2.2k 10k 2.7k 2.2k 2.2k 8.2k 8.2k 1k UDZ-TE-17-33B 4P 10k 18 1W 2.2 50V 10EDB40 10EDB40 10EDB40 10EDB40 10EDB40 10EDB40 10EDB40 2200 6.3V 0.1 0.1 0.1 0.1 0.1 100 16V 0.1 47k 4.7k 0.1 0.1 10 50V 0.01 0.01 RT8H015C-TH12-1 2SB1375 -33V REG 2SB1116 DTC114EKA B+ SWITCH RT1P137L B+ SWITCH TA78033LS +3.3V REG TA7804LS +3.9V REG TA7809LS +9V REG TA7809LS +9V REG 10k FA1L3Z 1SS355 2.2 50V 2200 25V EVER+3.3V M+9V M+7V EVER+4V STBY RLY D3.3V B1 CD-A+3.3V CD-D+3.3V B3 HP-L HP-R R-IN L-IN SPEANA A+9V GND DBFB F/B D+3.9V 23 75 84 83 78 81 94 49 29 30 4 73 74 39 FAN DC M891 DRIVE Q851,852 FAN MOTOR w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com HCD-GN600 40 40 7-11. PRINTED WIRING BOARD – GAME IN, CD SWITCH Board – • See page 26 for Circuit Boards Location. D748 H-12 D1001 E-9 D1002 D-10 D1003 D-10 D1004 C-10 D1005 C-9 D1006 B-9 D1007 C-8 D1008 C-8 D1009 D-8 D1010 D-8 D1011 E-8 IC603 B-11 IC722 D-2 Q721 E-3 Q748 H-11 Q1001 D-9 Q1002 D-10 Q1003 C-9 Q1004 C-8 Q1005 D-8 Q1006 D-8 • Semiconductor Location Ref. No. Location V V V V CN606 R604 C604 EP703 CN607 JW607 CLP704 R742 J721 C741 R737 C748 C742 JW602 R721 R740 JW603 R743 Q721 C737 R744 R734 C744 R739 R738 C717 C718 C606 C635 R605 C749 CLP702 C716 JW609 J601 JW601 C747 R746 R722 R602 R603 C715 JW605 C719 R736 C736 C738 JW604 R745 C739 C740 R735 RV722 C743 IC722 C630 C631 EP701 J631 JW608 JW764 JW613 C634 JW610 C720 R788 R789 NO603 S790 R790 S789 S788 D748 R748 S749 D748 R749 Q748 E S792 R792 S791 R791 S762 S750 S768 S767 R1001 S763 R762 R763 D1003 Q1001 Q1006 R1002 D1002 Q1002 R1003 R1004 JW1002 S760 S761 D1001 D1011 C751 C752 JW1001 C750 3 1 2 JW1003 JW1018 R765 C615 IC603 C614 3 2 1 S769 CN605 R625 R750 S771 JW1020 JW1007 JW1008 D1004 JW1009 JW1010 JW1019 D1005 R1005 JW1005 JW1004 R761 JW1014 E E E E E E R1011 R759 S748 JW1016 R760 D1010 D1009 Q1005 R1009 R1010 JW1015 S759 S766 S765 R776 R777 R775 R774 S773 JW1011 R766 R768 R769 R767 R770 Q1003 R1006 D1006 D1013 R772 R773 R771 R1007 R1008 D1008 Q1004 S770 D1007 JW1017 JW1013 JW1022 CLP703 VOLUME BOARD GAME IN BOARD CD SWITCH BOARD 11 (11) 1-686-936- 11 (11) 1-686-937- 11 (11) 1-686-935- PUSH ENTER MOVIE EQ EFFECT ON/OFF MUSIC EQ SURROUND EDIT/ DIRECTION FM MODE REPEAT TUNER MEMORY PLAY MODE AMP MENU DISPLAY VOL 4 VOLUME GROOVE ILLUMINATION VOL 11 P.FILE GAME EQ VOL 5 VOL 6 VOL 7 VOL 8 VOL 9 VOL 10 VOL 3 VOL 1 VOL 2 EX-CHANGE DISK SKIP DISC 3 DISC 2 DISC 1 Z OPEN/CLOSE PHONES MIC GAME INPUT MIC LEVEL AUDIO VIDEO L R 1 4 5 8 E C L MAIN BOARD (Page 36) DISPLAY BOARD (Page 42) J MAIN BOARD (Page 36) 1 9 M DISPLAY BOARD (Page 42) 2 3 4 5 6 7 8 9 10 11 12 13 A 1 B C D E F G H I w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com HCD-GN600 41 41 7-12. SCHEMATIC DIAGRAM – GAME IN, CD SWITCH Board – R773 R774 R775 R772 R770 R766 R771 R761 R760 R759 C615 R762 R767 R768 R769 R750 R765 R776 R777 R763 D1005 R1005 Q1005 Q1004 R1004 D1004 D1003 Q1003 D1002 R1002 Q1002 Q1001 R1001 D1001 D1010 R1010 R1009 D1009 D1008 R1008 D1007 R1007 Q1006 R1006 D1006 D1011 R1011 CN605 CLP703 S769 S770 S759 S761 C614 S762 S768 S763 C751 C752 R1003 R792 R791 R789 R790 R788 D748 R748 Q748 R742 R738 R737 R739 R743 C747 C741 C739 R735 IC722(1/2) IC722(2/2) C736 R736 R734 C737 C719 R745 R744 C715 C716 J631 R602 R603 C604 C606 EP703 EP701 CN607 R740 R749 CLP702 CN606 S791 S790 S792 S788 S789 S749 RV722 C738 R722 R721 C718 R746 R604 R605 NO603 S773 S771 S767 S766 S765 S760 C750 IC603 S748 C748 C744 C742 C740 C743 C749 R625 C717 J721 C635 C634 S750 C631 C630 Q721 J601 6.8k 10k 15k 4.7k 2.2k 680 3.3k 15k 10k 6.8k 47 10V 22k 1k 1.5k 1.5k 270 470 22k 33k 33k SLI-325URT31WT RED 470 BA1A4M BA1A4M 470 SLI-325URT31WT RED SLI-325URT31WT RED BA1A4M SLI-325URT31WT RED 470 BA1A4M BA1A4M 470 SLI-325URT31WT RED SLI-325URT31WT RED 470 470 SLI-325URT31WT RED SLI-325URT31WT RED 470 SLI-325URT31WT RED 470 BA1A4M 470 SLI-325URT31WT RED SLI-325URT31WT RED 470 17P FFC-L WIRE 0.001 0.1 0.1 470 33k 22k 10k 15k 6.8k SELS5223S RED 330 BA1A4M 1k 1k 22k 100k 10k 2.2 50V 0.15 50V 47p 50V 180k NJM4565D NJM4565D 10 50V 10k 100 10 50V 2.2 50V 100 100k 47p 47p 1k 1k 2.2 50V 2.2 50V 2P 2.2k 270 8P 50k 2.2 50V 18k 10k 100 10V 1k 100k 100k 5P AMP-L ROTARY SWITCH 0.1 VOLUME ENCODER 0.022 0.001 47p 100p 470p 0.1 47 100 10V 0.001 0.001 0.001 0.001 2SC2785TP BIAS 3P 55 54 53 52 56 57 52 53 54 55 56 57 VOLUME I/ I/ OPEN/CLOSE EX-CHANGE DISC SKIP R L AUDIO VIDEO 1 2 3 4 5 6 7 8 LED DRIVE Q1001-1006 LED DRIVE IC722 MIC AMP GAME INPUT w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com HCD-GN600 42 42 7-13. PRINTED WIRING BOARD – DISPLAY Board – • See page 26 for Circuit Boards Location. D100 D-6 D101 D-8 D102 C-8 D103 E-8 D104 E-8 D105 D-6 D106 E-4 D107 E-4 D601 F-2 D602 E-9 D603 D-9 D604 B-9 D605 C-9 D606 C-9 D610 A-2 IC101 D-7 IC102 F-9 IC601 B-5 Q100 D-6 Q601 G-2 Q602 B-9 Q603 C-9 Q604 D-9 Q605 F-2 Q606 F-2 Q707 G-2 Q807 B-7 Q808 B-7 • Semiconductor Location Ref. No. Location IC601 Y1 Y2 Q601 Q707 S758 R634 R635 R632 R633 D601 CN601 R631 JW701 R636 R637 JW702 Q606 S779 JW756 JW757 S755 S754 S753 S756 JW754 S757 JW709 JW715 JW716 R779 R654 R656 R655 JW714 JW717 JW718 JW703 JW704 JW705 Q605 JW707 JW706 D106 JW713 JW724 JW719 JW721 JW722 JW720 JW723 D107 JW725 JW760 R758 JW712 JW710 JW708 C620 C619 C710 C618 C711 L602 JW749 CLP701 R753 R754 S751 S752 R657 JW752 R751 R752 NO602 JW751 L601 R755 R756 R757 C652 C651 R647 C653 R645 D610 R646 JW753 R821 FL601 X601 R660 C623 JW748 JW763 R817 R818 R819 R820 Q807 Q808 JW759 JW700 R670 JW755 JW750 R663 R658 JW727 JW726 C622 R662 R661 JW729 JW758 JW738 JW737 JW740 JW739 JW728 C105 JW733 JW734 JW735 JW736 JW732 C712 JW108 R137 JW109 R140 JW107 R127 D100 C115 R128 D105 C110 C121 JW730 JW731 D102 R110 C106 C107 R108 R109 R105 R107 C109 C624 C625 C626 C627 C628 R808 R807 JW741 JW745 JW747 JW762 R112 Q602 Q603 D605 R626 R627 D604 R628 D606 JW743 JW742 R130 S784 D603 Q604 R106 R629 S783 R630 C122 R111 R113 R785 S785 S787 S786 R786 R787 JW746 JW744 R117 R132 R133 R129 IC101 R104 C101 C102 C104 R102 R103 D101 R119 R123 R125 C120 S782 R783 C119 R781 R782 R784 R114 R115 R116 IC102 C112 C111 R121 C116 C117 R120 R122 JW761 R659 C123 R822 R823 R136 R138 R139 Q100 JW106 C125 C152 C153 C118 JW113 C154 CN604 D602 JW105 JW102 R118 R124 C114 D103 D104 JW112 JW103 R131 JW104 R134 C100 C124 JW101 C155 C156 C157 R653 R652 CD TUNER/BAND TAPE A/B MD(VIDEO) GAME GAME MIXING x h h X > M > M ,ALBUM+ –, ,ALBUM– CD SYNC REC PAUSE/START ,+ E E E E E E E 1 100 50 51 81 80 30 31 1 4 5 8 11 (11) 1-686-934- DISPLAY BOARD M VOLUME BOARD (Page 40) I MAIN BOARD (Page 36) L CD SWITCH BOARD (Page 40) E E E 8 5 1 4 2 3 4 5 6 7 8 9 10 A 1 B C D E F G w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com HCD-GN600 43 43 7-14. SCHEMATIC DIAGRAM – DISPLAY Board – • See page 53 for Pin Function Description. FL601 CN601 D106 D107 S758 S756 S754 S753 S752 S751 S779 S782 S783 S784 S785 S786 S787 CN604 Q602 Q603 Q604 R632 R636 R634 R633 R637 R635 R670 D604 D601 D605 D606 D603 D602 D101 D102 D103 D104 D100 R130 R129 C122 R137 C124 R136 R139 C123 R140 R138 C118 D105 R127 R128 C121 C120 R125 R124 C119 R123 C114 R118 R119 R117 C115 C110 C105 R107 R113 R111 R106 R112 C109 C104 C107 R110 IC101(2/2) C106 R109 R108 R133 R132 R104 C102 C101 R102 R103 IC101(1/2) C653 C651 C652 R808 R807 C622 C712 C628 C627 C626 C625 C624 C711 C710 L602 C618 C620 C619 C112 R116 C111 R114 R115 R131 R134 R120 R121 C116 IC102(2/2) R122 C117 NO602 R105 R628 R626 R627 R629 R630 R779 R782 R781 R783 R784 R785 R786 R787 R631 R756 R755 R757 R754 R753 R752 R758 R751 R662 R663 R655 R656 R661 R652 R658 R659 R657 R654 R822 R823 C623 IC601 R660 R818 R819 R820 R821 R817 R647 R646 D610 R645 C153 C154 C155 C156 C157 C152 C125 S755 S757 X601 L601 R653 Q100 IC102(1/2) Q807 Q808 Q707 Q601 Q605 Q606 C100 19P FFC-S 10EDB40 10EDB40 17P FFC-L BA1A4M BA1A4M BA1A4M 680 10k 10k 680 10k 10k JW SEL5923A AMBER SLR325VC RED SEL5923A AMBER SEL5923A AMBER SEL5923A AMBER SEL5923A AMBER 1SS133T-72 1SS133T-72 1SS133T-72 1SS133T-72 MTZJ-T-72-3.3B 4.7k 4.7k 100 6.3V 22k 10 50V 68k 330 100 10V 100 1k 10 50V 1SS133T-72 220 470k 4.7 50V 0.22 50V 100k 100k 10 50V 680 10 50V 100k 100k 680 0.22 50V 0.22 50V 0.22 50V 100k 100k 680 100k 100k 10 50V 10 50V 0.1 47k NJM4565D 0.1 1.5k 1.5k 100k 100k 47k 0.47 0.47 1.5k 1.5k NJM4565D 10 50V 0.1 10 50V 100k 100k 4.7 50V 0.01 0.01 0.01 0.01 0.01 0.01 0.01 0.01 JW 0.01 0.01 47 10V 0.022 47k 0.022 1.5k 1.5k 100k 100k 1.5k 1.5k 0.0033 NJM4565D 47k 0.0033 5P AMP-L 680 330 330 330 330 330 470 1k 680 1.5k 1.5k 2.2k 3.3k 4.7k 680 2.2k 1.5k 3.3k 1.5k 1k 680 4.7k 470 10k 10k 100 100 10k 10k 15k 15k 15k 100 1k 1k 0.001 MB90M407PF-G-124 -BND 1M 180 180 180 120 120 100 100 MTZJ-T-72-5.1B 10k 220p 220p 220p 220p 220p 220p 0.1 50V 4MHz JW 10k 2SC3623 BUFFER NJM4565D BA1L3Z BA1L3Z BA1A4M INV. BA1A4M INV. 2SB1116 SWITCH 2SB1116 SWITCH 10 50V 66 65 48 60 61 69 70 71 73 68 12 13 14 15 16 17 18 19 20 21 22 24 25 26 27 28 29 30 10 9 8 7 6 5 4 3 2 1 100 99 98 97 96 95 94 66 79 80 77 77 93 87 88 89 90 91 92 52 53 54 55 56 57 58 59 31 32 33 34 35 36 37 38 39 40 41 43 44 61 60 49 51 64 48 72 73 72 67 67 68 69 70 71 8 9 10 12 13 14 15 16 17 18 19 20 21 22 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 44 45 46 7 6 5 4 3 2 1 100 99 98 97 96 95 92 91 90 89 88 87 45 46 43 59 58 93 94 79 65 80 52 53 54 55 56 57 64 FLUORESCENT INDICATOR TUBE REC PAUSE/START REC PAUSE/START + - ALBUM + ALBUM - DISPLAY BUFFER BUFFER KEY CONTROL CONTROL, LED DRIVE Q602-604 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com HCD-GN600 44 44 7-15. PRINTED WIRING BOARDS – POWER AMP Boards – • See page 26 for Circuit Boards Location. D501 E-3 D502 D-2 D503 D-4 D504 D-5 D506 C-7 D507 B-5 D508 H-2 D509 H-2 D511 B-5 D541 G-3 D543 H-4 D551 E-3 D581 F-2 IC501 D-4 Q501 E-4 Q503 G-2 Q504 F-2 Q505 B-2 Q506 B-2 Q510 F-6 Q511 F-6 Q514 B-2 Q516 H-5 Q517 H-5 Q518 B-2 Q551 E-4 Q581 F-2 • Semiconductor Location Ref. No. Location Q581 Q503 E E E Q504 C581 R561 R509 R559 C507 C508 C557 C558 TH501 Q514 R531 R522 Q506 Q505 D504 D503 R508 R558 Q501 Q551 R555 IC501 C516 Q510 C517 Q511 C546 C596 C542 C592 D541 R519 R581 CN503 C551 R551 R552 C553 R553 C554 R518 C552 C503 R503 C504 C509 R512 R511 R547 R548 D507 D511 C559 Q516 Q517 C526 R564 R565 D508 D509 R591 R541 R527 R521 D543 R542 R507 R505 C512 EP502 R513 D581 R517 R515 R514 R557 R592 CN504 R570 R569 R568 R572 R545 R546 R582 R516 R528 R506 R556 R554 D551 D501 R504 R529 R530 D502 JW780 JW781 JW783 JW785 JW786 JW787 JW788 JW790 JW791 JW792 JW793 JW794 JW795 JW796 JW797 JW798 JW799 JW800 JW801 JW802 JW803 JW804 JW805 JW806 JW807 JW809 JW810 JW811 JW812 JW813 JW814 JW816 JW817 JW818 JW820 JW821 JW822 JW823 JW824 JW828 JW829 JW830 JW831 JW832 JW833 JW834 JW835 JW836 JW837 JW838 JW840 JW841 JW842 JW843 JW844 JW847 JW848 JW849 JW850 JW851 JW852 JW853 JW854 JW855 JW856 JW857 JW858 JW859 JW860 JW861 JW862 JW863 JW864 JW865 JW866 JW867 JW868 JW869 JW870 JW874 JW878 JW879 JW880 JW881 JW882 JW815 PL005 PL006 PL007 R501 R502 C502 C501 JW819 RY501 D506 R539 C523 C524 EP501 C513 JW893 JW894 PL003 JW871 JW826 JW827 JW876 JW875 R520 R524 C541 C544 C545 JW789 C591 JW897 JW846 JW845 JW839 PL010 JW782 JW873 JW896 JW877 JW899 JW900 TH502 JW898 NO502 JW808 R523 R532 R533 R577 Q518 R578 JW927 JW926 E E E E E E E E 11 (11) 1-686-932- POWER AMP BOARD FRONT SPEAKER (IMPEDANCE USE 6–16Ω) TM501 + - + - L R + – + – D E MAIN BOARD (Page 36) MAIN BOARD (Page 36) 1 6 O TRANS BOARD (Page 46) E E 2 3 4 5 6 7 8 A 1 B C D E F G H w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com HCD-GN600 45 45 7-16. SCHEMATIC DIAGRAM – POWER AMP Boards – R501 R551 R504 D501 D551 R509 R559 R582 R581 C581 R561 Q506 Q505 C544 C545 R592 R533 R532 JW566 JW567 D506 Q510 R527 R528 R529 R530 C516 D507 CN503 CN504 D502 R508 R558 NO502 C502 C552 C501 C551 C554 C504 R512 R517 R516 R513 R515 R514 D581 R519 C559 C509 R521 R522 Q514 C512 RY501 R545 C524 C523 R548 R547 D511 TH502 TH501 R577 JW927 C596 R531 R557 R507 Q501 Q551 D503 D504 R503 R553 R511 D543 C546 R542 EP501 C542 R541 C592 R591 C591 C541 R502 R552 R554 R518 JW926 R565 R564 D509 D508 C517 R546 R570 R569 Q581 Q504 Q517 Q516 R572 R568 C526 C507 C508 Q511 C558 C557 EP502 C513 D541 R539 Q518 R578 R523 R555 R556 R524 IC501(2/2) IC501(1/2) C553 R506 R505 C503 R520 Q503 1k 1k 47k 1SS133T-72 1SS133T-72 10 1/2W 10 1/2W 33k 33k 22 50V 100 1/4W FR 2SC2785 2SC2785 0.1 100V 0.1 100V 100k 47k 100k 1SS133T 2SC2785 56k 47k 22k 22k 100 10V 1SS133T 13P 6P 1SS133T 0.1 5W 0.1 5W 1000p 1000p 4.7 50V 4.7 50V 100 10V 100 10V 1 1/4W FR 10k 10k 33k 22k 2.2k 1SS133T-72 68k 22 100V 22 100V 100k 100k 2SC2785 0.01 RELAY 24V 1k 0.01 25V 0.01 25V 47k 47k 1SS133T 100 2200 100V 330k 100k 100k 2SC1841 OVER LOAD DETECT 2SC1841 OVER LOAD DETECT MTZJ-T-72-18C MTZJ-T-72-18C 330 330 100 1/4W FR D5SBA20 2200 100V 100k TERMINAL, EARTH 3300 50V 100k 3300 50V 100k 0.1 0.1 47k 47k 47k 33k 22k 22k 1SS133T 1SS133T 10 50V 22k 10k 47k 2SC1841 STANDBY SWITCH 2SC1841 STANDBY SWITCH 2SA1175TP-HFE 2SC2785 100k 10k 10 50V 0.068 0.068 2SC2785 RELAY SWITCH 0.068 0.068 EARTH 0.1 D5SBA204101 330 2W 2SC2785 FAN MOTOR ON SWITCH 560k 82k 1k 27k 1k 1W STK412-240 POWER AMP STK412-240 POWER AMP 100p 27k 1k 100p 1k 1W 2SA988TP-TAFAEA STANDBY SWITCH R CH L CH R CH R GND L CH L GND VH VH VL VL - + - + R L (IMPEDANCE USE 6-16Ω) RELAY DRIVE FRONT SPEAKER RELAY DRIVE FRONT SPEAKER SWITCH OVER LOAD DETECT SWITCH DETECT Q505,506,514 TEMPERATURE SPEAKER TM501 4P w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com HCD-GN600 46 46 7-17. PRINTED WIRING BOARDS – TRANS Board – • See page 26 for Circuit Boards Location. • Semiconductor Location Ref. No. Location D971 B-4 D972 B-6 D973 B-6 D974 C-6 D975 C-6 D977 D-3 IC971 A-5 Q971 B-4 F978 F975 F977 R952 JW906 JW907 JW908 JW909 F974 PL002 PL008 R941 D977 C941 CN997 CN998 F976 PL009 JW912 JW911 JW913 NO973 JW928 JW929 C971 T972 S901 IC971 D974 D975 C973 D971 Q971 RY971 CN974 C975 C976 C977 JW921 D972 D973 C978 R974 R975 PL001 PL004 JW920 JW924 JW925 B100 CN976 CN971 E TRANS BOARD SUB TRANS BOARD 11 (11) 1-686-930- 11 (11) 1-686-931- 1 2 3 4 1 1 7 1 6 4 1 4 1 3 1 2 AC IN 120V 220V 230-240V t t VOLTAGE SELECTOR * * NOT REPLACEABLE: BUILT IN TRANSFORMER T910 POWER TRANSFORMER H O MAIN BOARD (Page 36) POWER AMP BOARD (Page 44) F MAIN BOARD (Page 36) 2 3 4 5 6 7 A 1 B C D E F w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com HCD-GN600 47 47 7-18. SCHEMATIC DIAGRAM – TRANS Board – CN974 D975 D973 D972 D974 NO973 CN998 CN976 RY971 D971 C975 R975 C973 R974 C978 C977 C976 C971 JW920 T972 CN997 JW928 JW929 F976 F977 F974 F975 R952 C941 F978 D977 JW924 S901 JW912 JW911 JW913 T910 IC971 Q971 CN971 R941 2P VH 11ES2 11ES2 11ES2 11ES2 4P 1SS133T 2200 16V 10k 100 16V 100k 0.1 0.1 0.1 10000p T8.0AL/250V T8.0AL/250V T6.3AL/250V T6.3AL/250V 0.15 1/4W 100 63V T4.0AL/250V 11ES2 TA7804LS +3.9V REG 2SC2785 4P 1 VOLTAGE SELECTOR 120V 220V 230-240V POWER TRANSFORMER BUILT IN TRANSFORMER NOT REPLACEABLE: * * AC IN RELAY DRIVE POWER ON/OFF w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com HCD-GN600 48 48 7-19. IC Block Diagrams IC103 CXA2647N-T4 (CD BOARD) IC101 CXD3068Q (CD BOARD) IC701 BA6956AN (DRIVER BOARD) IC712 BA6956AN (DRIVER BOARD) RW/ROM RW/ROM EQ ON/OFF VOFST VOFST DVC VC VC VC RW/ROM VC DVC 30 29 28 + – + – DVC VCC DVC 27 26 25 24 RW/ROM EQ 23 22 21 20 19 RFAC VCA VCC + – DVC + – + – RW/ROM VC RW/ROM DVC + – 3 A B C D B C A A A B C D B C D D + – 1 2 APC AMP 5 6 7 8 9 4 RFAC SUMMING AMP RW/ROM APC-OFF (Hi-Z) RW/ROM (H/L) VOFST VC RW/ROM + – 10 11 GM GM 18 17 16 B D A C 13 14 15 12 EQ IN LD PD GND A B C D AC SUM E F DVCC DVC RFAC SW DC OFST RFDCI RFDCO VC RFC VFC BST RFG VCC CEI CE TE BAL TE FEI FE CE RFDC ADIO IGEN ASYO ASYI RFAC CLTV FILO FILI PCO BIAS VCTL V16M VPCO TE ASYE MD2 DOUT LRCK PCMD BCK EMPH XTSL XTAI XTAO SOUT SOCK XOLT SQSO SQCK SCSY SBSO EXCK XRST MUTE DATA XLAT CLOK SENS SCLK ATSK WFCK XUGF XPCK GFS C2PO SCOR CAM WDCK COUT MIRR SE FE VC TES1 TEST FFDR TRDR TFDR SRDR SFDR FSTO SSTP LOCK PWMI FOK FRDR MDP DFCT CLOCK GENERATOR ASYMMETRY CORRECTOR DIGITAL PLL CPU INTERFACE INTERFACE CORRECTOR PROCESSOR SUB CODE RAM 32K DEMODURATOR EFM ERROR D/A DIGITAL OUT INTERFACE SERVO INTERFACE SERVO AUTO MIRR DFCT FOK SERVO FOCUS SERVO DSP SERVO SERVO SLED TRACKING FOCUS PWM GENERATOR GENERATOR GENERATOR SLED PWM TRACKING PWM A/D CONVERTER OPAMP ANALOG SW PWM GENERATOR DIGITAL CLV SERVO BLOCK IC150 BA5974FM-E2 (CD BOARD) LEVEL SHIFT INTERFACE INTERFACE INTERFACE 1 2 3 4 5 6 7 8 9 10 11 12 13 14 20 21 22 23 24 25 26 27 28 19 18 17 16 15 F R R F F R R F R R F F MUTE THERMAL SHUTDOWN VREFOUT VREFIN POWVCC CH1FIN CH1RIN CH2FIN CH2RIN CH2OUTR CH2OUTF CH1OUTR CH1OUTF CAPAIN1 CAPAIN2 GND PRFVCC MUTE POWVCC CH4SIN' CH4SIN CH4BIN CH3FIN CH3RIN CH3OUTR CH3OUTF CH4OUTR CH4OUTF CAPAIN3 GND 1 2 3 4 5 6 7 8 9 CONTROL LOGIC TSD VREF OUT2 OUT1 RNF VM VCC FIN GND RIN w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 49 HCD-GN600 7-20. IC Pin Function Description • IC104 CXD9717R-008 D/A Converter, MP3 Decoder (CD Board) Pin No. 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 to 34 35 36 37 38 39 40 41 42 43 44 45 46, 47 48 49, 50 51 52 53 I/O I I I I I/O I O – O O O I I I I I I – I – – – O – – O – – I O O – O O O O – I – I I – I – I I – I Pin Name RESET MIMD MICS/AD0 MILP/AD1 MIDIO MICK MIACK/AD2 VDDT SDO BCKO/AD3 LRCKO/AD4 SDI0 BCKIA LRCKIA SDI1/AD5 BCKIB/CE LRCKIB/OE VDD STANDBY VSS VSSL VRAL LO VDAL VDAR RO VRAR VSSR TESTP CSK PO0/AD12 to PO3/AD09 VDDT PO4/AD8 PO5/AD7 PO6/AD6 PO7 VSS FI0/AD13 FI1/AD14/VDDM FI2/WR FI3/AD16 VSSM PI0, PI1 VSS PI2/IO2, PI3/IO3 PI4/IO4 VDD PI5/IO5 Description Reset input terminal “L”: reset Microcomputer interface mode selection input “H”: I2C, “L”: TSB (fixed at “L”) Microcomputer interface chip select signal input Microcomputer interface latch pulse input Serial data input/output Serial clock input Microcomputer interface acknowledge signal output Power supply (3.3V) for digital circuit Data output (open) Bit output (open) LR clock output (open) Data input 0 Bit clock input A LR clock input A Data input 1 (fixed at “L”) Bit clock input B (fixed at “L”) LR clock input B (fixed at “L”) Power supply (2.5V) for digital circuit Standby mode control signal input “H”: STB, “L”: normal (fixed at “H”) Ground for digital circuit Ground for DAC Lch Reference voltage terminal for DAC Lch DAC Lch signal output Power supply (2.5V) for DAC Lch Power supply (2.5V) for DAC Rch DAC Rch signal output Reference voltage terminal for DAC Rch Ground for DAC Rch Terminal for test “H”: test mode, “L”: normal (fixed at “L”) SPDIF signal output (open) General purpose output (open) Power supply (3.3V) for digital circuit General purpose output (open) General purpose output (open) General purpose output (open) Interrupt request signal output to the system control Ground for digital circuit External interrupt signal input (fixed at “L”) Power supply (2.5V) for the internal 1Mbit SRAM Flag signal input 0 (fixed at “L”) Flag signal input 1 (fixed at “L”) Ground for the internal 1Mbit SRAM General purpose input (fixed at “L”) Ground for digital circuit General purpose input (fixed at “L”) General purpose input (fixed at “L”) Power supply (2.5V) for digital circuit General purpose input/SUBQ interface data input (fixed at “L”) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 50 HCD-GN600 Pin No. 54 55 56 57 58 59 60 61 62 63 64 I/O I I – O I – O – I O – Pin Name BOOT/IO6 TXO/IO7 VSSP PDO VCOI VDDP CKO VDDX XI XO VSSX Description Terminal for test/SUBQ interface frame sync input (fixed at “L”) Flag signal input 2/SUBQ interface block sync input (fixed at “L”) Ground for VCO circuit PLL phase error detection signal output VCO control voltage input Power supply (2.5V) for VCO circuit External clock output Power supply (2.5V) for oscillation circuit Resonator terminal (input) Resonator terminal (output) Ground for oscillation circuit www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 51 HCD-GN600 Description Pin Name Pin No. I/O 1 MP3 CS O MP3 chip select signal output 2 MP3 LP O MP3 latch pules output 3 MP3 ACK I MP3 acknowledge signal input 4 SIRCS I SIRCS input 5 MP3 DATA OUT O Serial data output 6 MP3 DATA IN I Serial data input 7 MP3 CLK O Serial clock output 8 BYTE I Not used (connected to ground) 9 CNVSS — Not used (Connected to ground with resistor) 10 XC-IN I Sub clock input 11 XC-OUT O Sub clock output 12 RESET I System reset input 13 X-OUT O Main system clock output (16MHz) 14 VSS — Ground 15 X-IN I Main system clock input (16MHz) 16 VCC — Power supply (+5V) 17 NMI I Not used (Pull up with resistor) 18 MP3 REQ I Interrupt request signal input 19 SCOR I Subcode sync (S0+S1) detection signal input 20 AC-CUT I AC cut check signal input 21 E-1 I Disc tray status detection signal input 22 E-2 I Disc tray status detection signal input 23 CD-POWER O CD power on/off signal output 24 BU-PWM3 O BU PWM 3 (for CD-RW) signal output 25 CD-A-MUTE O CD mute signal output 26 BU-PWM2 O BU PWM 2 (for CD-RW) signal output 27 STBY-RELEY O Reley drive signal output 28 BU-PWM1 O BU PWM 1 (for CD-RW) signal output 29 IIC-CLK I IIC serial data clock input 30 IIC-DATA I IIC serial data input 31 TXD1 — Not used 32 SQ-DATA I Subcode Q data input 33 SQ-CLK O Subcode Q data reading clock signal output 34 SENS I SENS signal input from CXD3068Q 35 CD-DATA O CD data output 36 XLAT O CD latch signal output 37 CD-CLK O CD data clock output 38 LD-ON O Laser diode control signal output 39 STBY-LED O Standby LED drive signal output 40 XRST O CD reset signal output 41 TBL-SENS I Table sensor signal input 42 EJECTSW I Eject switch signal input 43 E-3 I Disc tray status detection signal input 44 TM-F O Table motor control signal output 45 TM-R O Table motor control signal output 46 LMF O Loading motor control signal output 47 LMR O Loading motor control signal output 48 MP3 RESET O MP3 reset signal output 49 GC-RESET O GC reset signal output 50 HP DETECT I Headphone detect input ––––––––––––––––––––– 51 REC-MUTE O REC mute signal output 52 TC-MUTE O TC line mute signal output 53 PB-A/B O TC A/B select signal output • IC501 M30622MGN-B14FP SYSTEM CONTOL (MAIN Board) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 52 HCD-GN600 Pin Name Pin No. I/O Discription 54 ALC O ALC signal output 55 TC-RELAY O REC/PB selection signal output 56 REC BIAS O Bias on/off signal output 57 CAPM-CONT O Capstan motor REV/FWD/STOP control signal output 58 B-TRIG O TCM-B Trigger output 59 A-TRIG O TCM-A trigger output 60 B-REC, REV O Record tab switch for SIDE B signal output 61 B-PLAY I TCM-B play switch input 62 VCC — Power supply (+3.3V) –––––––––––––– 63 AMS-IN I AMS signal input 64 VSS — Ground 65 ST-DIN I Tuner data input 66 A-REC, FWD O Record tab switch for SIDE A signal output 67 A-HALF I A deck half detection signal input 68 A-PLAY I TCM-A play switch input 69 LED-SW-LINK O Subwoofer LED drive signal output (open) 70 LED-SW-ON O Subwoofer LED drive signal output (open) 71 LED-MATRIX-SURR-2 O Subwoofer LED drive signal output (open) 72 LED-MATRIX-SURR-1 O Subwoofer LED drive signal output (open) 73 KEY-DISPLAY I DISPLAY key signal input 74 POWER-KEY I Power key signal input 75 STK-MUTE O Mute signal output to power IC –––––––––––––––––– 76 HP-MUTE O Headphone mute signal output 77 LINE-MUTE O TA LINE mute signal output –––––––––––––––––– 78 PROTECT I Speaker protection signal input 79 AUDIO-DATA O Serial data output to Audio EQIC 80 AUDIO-CLK O Serial data clock output to Audio EQIC –––––––––––––––– 81 VACS IN I VACS signal input 82 SW-RELAY O Subwoofer relay control signal output (open) 83 FRONT-RELAY O Front speaker relay driver signal output 84 LINK-RELAY O Surround speaker relay driver signal output ––––––––––––––– 85 STEREO I Stereo signal input –––––––––––––– 86 TUNED I Tuned signal input 87 ST-CE O Tuner chip enable signal output 88 ST-DOUT O Tuner data output 89 A-SHUT I TCM-A reel pulse input 90 B-SHUT I TCM-B reel pulse input 91 B-HALF I B deck half detection input 92 MODEL-IN I Model input 93 DEST-IN I Destination input 94 I-HOLD I Over-voltage protection detection input termnal 95 SW-AD-KEY I Subwoofer key signal input (fixed at “H”) 96 AVSS — Ground 97 ST-CLK O Tuner clock signal output 98 VREF I Reference voltage input 99 AVCC — Power supply (+3.3V) 100 ST-MUTE O Tuner mute signal output www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 53 HCD-GN600 • IC601 MB90M407APF-G-124-BND DISPLAY CONTROL (DISPLAY Board) Description Pin Name Pin No. I/O 1 to 7 G7 to G1 O FLD grid output 8 to 10 P1 to P3 O FLD segment output 11 VSS-IO — Ground 12 to 22 P4 to P14 O FLD segment output 23 VDD-FIP — Power supply (+3.3V) 24 to 41 P15 to P32 O FLD segment output 42 VSS-IO — Ground 43 to 46 P32 to P36 O FLD segment output 47 NO USED O Not used 48 VKK — Power supply (-35V) 49 MD0 I Not used (pull up with resistor) 50 MD1/VDD-VFT I Not used (pull up with resistor) 51 MD2 I Not used (pull down with resistor) 52 VOLUME5,6 LED O LED drive signal output 53 VOLUME7,8 LED O LED drive signal output 54 VOLUME9,10 LED O LED drive signal output 55 VOLUME11,MULTI CH LED O LED drive signal output 56 VOLUME3,4 LED O LED drive signal output 57 VOLUME1,2 LED O LED drive signal output 58 TAPE A/B,TUNER LED O LED drive signal output 59 GAME,MD/VIDEO LED O LED drive signal output 60 I2C-DATA O IIC serial data output 61 I2C-CLOCK O IIC clock signal output 62 AVCC — Power supply (+3.3V) 63 AVSS — Ground 64 to 66 KEY0 to KEY2 I Key input (A/D port) 67 to 70 BPF3 to BPF0 I Spectrum analyzer BPF signal input 71 ALL BAND I L+R signal input 72 SELECTOR O LED group select signal output 73 CD/DVD, REC/PAUSE LED O LED drive signal output 74 to 76 NO USE O Not used 77 RESET I Reset input 78 SOFT TEST O Not used (open) 79 VOL 1B I Volume encoder signal B input 80 VOL 1A I Volume encoder signal A input 81 VSS-CPU — Ground 82 XOUT O Crystal oscillator output (4MHz) 83 XIN I Crystal oscillator input (4MHz) 84 VCC-CPU — Power supply (+3.3V) 85, 86 NO USE — Not used 87 to 100 G21 to G8 O FLD grid output www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 54 HCD-GN600 8-1. CASE, REAR PANEL SECTION SECTION 8 EXPLODED VIEWS The components identified by mark 0 or dotted line with mark 0 are critical for safety. Replace only with part number specified. NOTE: • -XX and -X mean standardized parts, so they may have some difference from the original one. • Items marked “*” are not stocked since they are seldom required for routine service. Some delay should be anticipated when ordering these items. • Accessories are given in the last of the elec- trical parts list. • Abbreviation AR : Argentine model E2 : 120 V AC Area in E model E51 : Chilean and Peruvian model MX : Mexican model Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 1 4-244-102-01 LOADING (PANEL) 2 3-363-099-41 SCREW (CASE 3 TP2) 3 4-231-828-31 CASE 4 A-4731-346-A SUB TRANS BOARD, COMPLETE 5 1-920-838-32 WIRE (FLAT TYPE) (11 CORE) 6 1-693-603-11 TUNER (FM/AM) M891 1-763-072-11 FAN, DC #1 7-685-647-79 SCREW +BVTP 3X10 TYPE2 N-S #2 7-685-871-09 SCREW +BVTT 3X6 (S) 1 M891 not supplied not supplied not supplied 2 3 4 5 6 #1 #1 #1 #1 #1 #1 #1 #1 #1 #2 #2 #2 #2 #2 #2 #1 #1 2 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 55 HCD-GN600 8-2. FRONT PANEL SECTION Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 51 X-4955-228-1 FRONT PANEL ASSY 52 4-225-252-01 CUSHION (FOOT) 53 4-244-075-01 HOLDER (TC-R) 54 4-244-093-01 SPRING (LID) 55 4-244-072-01 LID (TC) 56 4-244-073-01 WINDOW (TC) 57 4-244-090-01 COVER (AL-TC) 58 4-244-074-01 HOLDER (TC-L) 59 4-224-578-21 KNOB (MIC) 60 4-244-097-01 KNOB (VOL) 61 4-244-089-01 COVER (AL-STR) 62 4-951-620-01 SCREW (2.6X8), +BVTP 63 4-963-404-21 EMBLEM (5-A), SONY 64 4-224-104-11 DAMPER 65 4-244-094-01 SPRING (L) 66 4-244-095-01 SPRING (R) 67 1-686-936-11 CD SWITCH BOARD 68 A-4731-329-A VOLUME BOARD, COMPLETE 69 4-244-096-01 KNOB (CURSOR) 70 1-773-040-11 WIRE (FLAT TYPE) (17 CORE) 71 A-4731-353-A DISPLAY BOARD, COMPLETE 72 4-231-581-01 HOLDER (FL) 73 1-773-110-11 WIRE (FLAT TYPE) (19 CORE) 74 A-4731-327-A GAME IN BOARD, COMPLETE 75 1-796-487-31 DECK, MECHANICAL 76 4-243-609-01 BELT (AF) 77 4-243-610-01 BELT (AL) 78 4-243-608-01 BELT (BR) 79 1-751-688-11 WIRE (FLAT TYPE) (13 CORE) 80 3-378-434-01 CUSHION, SARANET FL601 1-518-862-11 INDICATOR TUBE, FLUORESCENT #4 7-685-781-09 SCREW +PTT 2X4 (S) 57 56 55 54 53 52 77 76 79 78 75 62 62 62 74 62 71 62 62 62 70 68 67 69 62 51 73 72 64 66 65 80 80 80 64 63 62 61 58 59 60 supplied with S748 not supplied not supplied not supplied FL601 #4 #4 62 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 56 HCD-GN600 8-3. CHASSIS SECTION Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark The components identified by mark 0 or dotted line with mark 0 are critical for safety. Replace only with part number specified. 101 1-686-930-11 TRANS BOARD 0103 1-777-071-53 CORD, POWER (E51) 0103 1-783-941-12 CORD, POWER (AR) 0103 1-791-901-12 CORD, POWER (E2,MX) * 104 3-703-244-00 BUSHING (2104), CORD (AR,E51) 104 3-703-571-11 BUSHING (S) (4516), CORD (E2,MX) 105 A-4731-339-A MAIN BOARD, COMPLETE 106 4-225-252-01 CUSHION (FOOT) 107 A-4731-347-A POWER AMP BOARD, COMPLETE 108 4-943-687-01 HOLDER, PC BOARD * 109 4-988-533-01 HOLDER, PWB 0F974 1-533-473-11 FUSE, GLASS TUBE (DIA. 5) (T6.3AL 250V) 0F975 1-533-473-11 FUSE, GLASS TUBE (DIA. 5) (T6.3AL 250V) 0F976 1-533-473-11 FUSE, GLASS TUBE (DIA. 5) (T6.3AL 250V) 0F977 1-533-473-11 FUSE, GLASS TUBE (DIA. 5) (T6.3AL 250V) 0F978 1-533-471-11 FUSE, GLASS TUBE (DIA. 5) (T4AL 250V) 0T910 1-439-556-11 POWER TRANSFORMER #1 7-685-647-79 SCREW +BVTP 3X10 TYPE2 N-S #3 7-685-650-79 SCREW +BVTP 3X16 TYPE2 IT-3 #5 7-685-881-09 SCREW +BVTT 4X8 (S) 107 108 103 104 105 109 106 101 not supplied not supplied not supplied F976 T910 F977 F975 F978 F974 not supplied #5 #5 #1 #1 #3 #1 #1 #1 #1 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 57 HCD-GN600 Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 8-4. CD MECHANISM DECK SECTION-1 (CDM74-K6BD47S) 151 4-218-253-21 SCREW (M2.6), +BTTP 152 1-776-182-11 WIRE (FLAT TYPE) (5 CORE) 153 1-687-134-11 MOTOR (TB) BOARD 154 4-243-815-01 TABLE (LOADING) 155 4-245-571-01 GEAR (STOPPER) 156 4-218-252-61 SCREW (+PTPWH M2.6), FLOATING 157 4-245-570-01 GEAR (JOINT) 158 4-245-572-01 BUSHING (GEAR) 159 1-687-132-11 SENSOR BOARD 160 4-243-820-01 GEAR (TABLE) 161 4-243-819-01 GEAR (GENEVA) 162 4-243-816-01 TRAY 163 4-243-823-01 BELT (TABLE) 164 4-985-672-01 SCREW (+PTPWH M2.6), FLOATING 165 4-243-821-01 PULLEY (TABLE) M741 A-4723-963-A MOTOR ASSY, TABLE 151 152 153 154 155 155 156 156 157 157 158 158 159 151 156 162 163 164 165 160 161 164 M741 chassis assy www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 58 HCD-GN600 Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 201 1-687-135-11 DRIVER BOARD 202 4-218-253-31 SCREW (M2.6), +BTTP 203 1-687-669-11 SW BOARD 204 4-244-034-01 BELT (LOADING) 205 4-218-252-61 SCREW (+PTPWH M2.6), FLOATING 206 4-225-844-01 GEAR (LOADING A) 207 4-224-613-01 GEAR (SHAFT) 208 1-687-133-11 MOTOR (LD) BOARD 210 4-244-108-01 GEAR, SWING 211 4-224-609-01 GEAR (LOADING C) 212 4-224-608-01 COLLAR, SWING 213 3-016-533-01 WASHER (FR), STOPPER 214 4-224-611-01 GEAR (LOADING B) 215 4-224-606-01 GEAR (RV) 216 4-243-818-01 GEAR (U/D) 217 4-243-822-01 LEVER (LIFTER) 218 X-4955-774-1 PULLEY (SM) ASSY, CHUCKING 219 4-221-688-01 PULLEY (B), CHUCKING 220 X-4955-536-1 HOLDER (213) ASSY 222 4-277-549-11 INSULATOR 223 4-277-045-11 SPRING (INSULATOR), COIL 224 4-231-151-01 STOPPER (SU) 225 4-218-253-31 SCREW (M2.6), +BTTP 226 1-782-817-11 WIRE (FLAT TYPE) (16 CORE) 227 1-775-280-11 WIRE (FLAT TYPE) (31 CORE) 228 A-4731-446-A CD BOARD, COMPLETE 0229 A-4735-357-A BASE ASSY, OP (including KSS-213DCP) 230 1-471-035-11 MAGNET ASSY 231 4-243-817-11 CHASSIS M751 A-4737-553-A MOTOR ASSY, LOADING RE701 1-477-680-11 ENCODER, ROTARY #6 7-685-534-19 SCREW +BTP 2.6X8 TYPE2 N-S 8-5. CD MECHANISM DECK SECTION-2 (CDM74-K6BD47S) 201 202 202 202 203 204 205 206 207 208 210 211 212 213 214 215 216 217 219 231 220 205 205 222 223 223 224 224 225 226 227 228 230 218 223 223 222 229 222 222 205 205 205 205 M751 RE701 #6 The components identified by mark 0 or dotted line with mark 0 are critical for safety. Replace only with part number specified. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 59 Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks HCD-GN600 SECTION 9 ELECTRICAL PARTS LIST Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks CD NOTE: • Due to standardization, replacements in the parts list may be different from the parts speci- fied in the diagrams or the components used on the set. • -XX and -X mean standardized parts, so they may have some difference from the original one. • RESISTORS All resistors are in ohms. METAL: Metal-film resistor. METAL OXIDE: Metal oxide-film resistor. F: nonflammable • Items marked “*” are not stocked since they are seldom required for routine service. Some delay should be anticipated when order- ing these items. • SEMICONDUCTORS In each case, u: µ, for example: uA. . : µA. . uPA. . : µPA. . uPB. . : µPB. . uPC. . : µPC. . uPD. . : µPD. . • CAPACITORS uF: µF • COILS uH: µH The components identified by mark 0 or dotted line with mark 0 are critical for safety. Replace only with part number specified. When indicating parts by reference number, please include the board. • Abbreviation AR : Argentine model E2 : 120 V AC Area in E model E51 : Chilean and Peruvian model MX : Mexican model A-4731-446-A CD BOARD, COMPLETE ******************* < CAPACITOR > C101 1-164-315-11 CERAMIC CHIP 470PF 5% 50V C102 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C103 1-164-315-11 CERAMIC CHIP 470PF 5% 50V C104 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V C107 1-162-919-11 CERAMIC CHIP 22PF 5% 50V C108 1-164-360-11 CERAMIC CHIP 0.1uF 16V C109 1-164-360-11 CERAMIC CHIP 0.1uF 16V C110 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C111 1-126-209-11 ELECT CHIP 100uF 20% 4V C113 1-126-209-11 ELECT CHIP 100uF 20% 4V C114 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C115 1-126-246-11 ELECT CHIP 220uF 20% 4V C116 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C117 1-164-360-11 CERAMIC CHIP 0.1uF 16V C118 1-115-156-11 CERAMIC CHIP 1uF 10V C119 1-115-156-11 CERAMIC CHIP 1uF 10V C131 1-110-563-11 CERAMIC CHIP 0.068uF 10% 16V C132 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V C133 1-125-838-11 CERAMIC CHIP 2.2uF 10% 6.3V C150 1-128-995-21 ELECT CHIP 100uF 20% 10V C151 1-164-360-11 CERAMIC CHIP 0.1uF 16V C152 1-164-360-11 CERAMIC CHIP 0.1uF 16V C158 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V C202 1-164-360-11 CERAMIC CHIP 0.1uF 16V C203 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C205 1-164-360-11 CERAMIC CHIP 0.1uF 16V C206 1-126-607-11 ELECT CHIP 47uF 20% 4V C208 1-164-360-11 CERAMIC CHIP 0.1uF 16V C209 1-162-927-11 CERAMIC CHIP 100PF 5% 50V C211 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C212 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V C213 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V C215 1-117-863-11 CERAMIC CHIP 0.47uF 10% 6.3V C216 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C222 1-164-360-11 CERAMIC CHIP 0.1uF 16V C223 1-126-607-11 ELECT CHIP 47uF 20% 4V C224 1-164-360-11 CERAMIC CHIP 0.1uF 16V C226 1-126-607-11 ELECT CHIP 47uF 20% 4V C227 1-164-360-11 CERAMIC CHIP 0.1uF 16V C229 1-164-360-11 CERAMIC CHIP 0.1uF 16V C230 1-164-360-11 CERAMIC CHIP 0.1uF 16V C231 1-126-209-11 ELECT CHIP 100uF 20% 4V C249 1-162-974-11 CERAMIC CHIP 0.01uF 50V C250 1-164-360-11 CERAMIC CHIP 0.1uF 16V C251 1-164-360-11 CERAMIC CHIP 0.1uF 16V C252 1-164-360-11 CERAMIC CHIP 0.1uF 16V C253 1-164-360-11 CERAMIC CHIP 0.1uF 16V C254 1-162-919-11 CERAMIC CHIP 22PF 5% 50V C255 1-164-360-11 CERAMIC CHIP 0.1uF 16V C256 1-164-360-11 CERAMIC CHIP 0.1uF 16V C257 1-165-112-11 CERAMIC CHIP 0.33uF 16V C258 1-162-919-11 CERAMIC CHIP 22PF 5% 50V C259 1-164-361-11 CERAMIC CHIP 0.047uF 16V C260 1-126-246-11 ELECT CHIP 220uF 20% 4V C261 1-126-607-11 ELECT CHIP 47uF 20% 4V C262 1-126-607-11 ELECT CHIP 47uF 20% 4V C263 1-125-822-11 TANTAL. CHIP 10uF 20% 10V C264 1-126-607-11 ELECT CHIP 47uF 20% 4V C265 1-126-607-11 ELECT CHIP 47uF 20% 4V C266 1-164-360-11 CERAMIC CHIP 0.1uF 16V C267 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V C268 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V C269 1-125-822-11 TANTAL. CHIP 10uF 20% 10V C270 1-162-960-11 CERAMIC CHIP 220PF 10% 50V C271 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C273 1-162-960-11 CERAMIC CHIP 220PF 10% 50V C274 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C275 1-126-246-11 ELECT CHIP 220uF 20% 4V C276 1-126-209-11 ELECT CHIP 100uF 20% 4V C279 1-100-588-21 ELECT CHIP 1000uF 20% 6.3V C292 1-115-156-11 CERAMIC CHIP 1uF 10V < CONNECTOR > CN101 1-784-387-11 CONNECTOR, FFC/FPC 31P CN102 1-777-937-11 CONNECTOR, FFC/FPC 16P < FERRITE BEAD > FB101 1-500-283-11 FERRITE 0uH FB102 1-500-283-11 FERRITE 0uH FB103 1-500-283-11 FERRITE 0uH FB104 1-500-283-11 FERRITE 0uH FB106 1-500-283-11 FERRITE 0uH FB107 1-500-283-11 FERRITE 0uH FB291 1-500-283-11 FERRITE 0uH < IC > IC101 8-752-408-73 IC CXD3068Q www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 60 Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks HCD-GN600 CD DISPLAY IC103 8-752-106-21 IC CXA2647N-T4 IC104 6-704-150-01 IC CXD9717R-008 IC121 6-700-394-01 IC BA25BC0FP-E2 IC150 8-759-677-90 IC BA5947FP-E2 < COIL > L101 1-412-063-21 INDUCTOR 68uH < TRANSISTOR > Q101 8-729-046-90 TRANSISTOR 2SB970-(TX).S0 < RESISTOR > R101 1-216-864-11 METAL CHIP 0 5% 1/10W R102 1-216-833-11 METAL CHIP 10K 5% 1/10W R103 1-216-845-11 METAL CHIP 100K 5% 1/10W R104 1-216-833-11 METAL CHIP 10K 5% 1/10W R105 1-216-821-11 METAL CHIP 1K 5% 1/10W R111 1-216-847-11 METAL CHIP 150K 5% 1/10W R113 1-216-828-11 METAL CHIP 3.9K 5% 1/10W R114 1-216-852-11 METAL CHIP 390K 5% 1/10W R117 1-216-846-11 METAL CHIP 120K 5% 1/10W R118 1-216-833-11 METAL CHIP 10K 5% 1/10W R120 1-216-846-11 METAL CHIP 120K 5% 1/10W R122 1-216-845-11 METAL CHIP 100K 5% 1/10W R123 1-216-791-11 METAL CHIP 3.3 5% 1/10W R125 1-216-836-11 METAL CHIP 18K 5% 1/10W R126 1-216-836-11 METAL CHIP 18K 5% 1/10W R131 1-216-843-11 METAL CHIP 68K 5% 1/10W R132 1-216-851-11 METAL CHIP 330K 5% 1/10W R133 1-216-825-11 METAL CHIP 2.2K 5% 1/10W R151 1-216-833-11 METAL CHIP 10K 5% 1/10W R152 1-216-849-11 METAL CHIP 220K 5% 1/10W R153 1-216-864-11 METAL CHIP 0 5% 1/10W R155 1-216-864-11 METAL CHIP 0 5% 1/10W R156 1-216-864-11 METAL CHIP 0 5% 1/10W R201 1-216-839-11 METAL CHIP 33K 5% 1/10W R202 1-216-833-11 METAL CHIP 10K 5% 1/10W R203 1-216-845-11 METAL CHIP 100K 5% 1/10W R204 1-216-825-11 METAL CHIP 2.2K 5% 1/10W R205 1-216-821-11 METAL CHIP 1K 5% 1/10W R206 1-216-825-11 METAL CHIP 2.2K 5% 1/10W R207 1-216-857-11 METAL CHIP 1M 5% 1/10W R212 1-216-817-11 METAL CHIP 470 5% 1/10W R213 1-216-817-11 METAL CHIP 470 5% 1/10W R214 1-216-864-11 METAL CHIP 0 5% 1/10W R215 1-216-864-11 METAL CHIP 0 5% 1/10W R216 1-216-857-11 METAL CHIP 1M 5% 1/10W R218 1-216-821-11 METAL CHIP 1K 5% 1/10W R219 1-216-821-11 METAL CHIP 1K 5% 1/10W R220 1-216-821-11 METAL CHIP 1K 5% 1/10W R230 1-216-813-11 METAL CHIP 220 5% 1/10W R231 1-216-809-11 METAL CHIP 100 5% 1/10W R232 1-216-809-11 METAL CHIP 100 5% 1/10W R233 1-216-809-11 METAL CHIP 100 5% 1/10W R249 1-216-817-11 METAL CHIP 470 5% 1/10W R250 1-216-813-11 METAL CHIP 220 5% 1/10W R251 1-216-813-11 METAL CHIP 220 5% 1/10W R252 1-216-857-11 METAL CHIP 1M 5% 1/10W R253 1-216-819-11 METAL CHIP 680 5% 1/10W R254 1-216-845-11 METAL CHIP 100K 5% 1/10W R255 1-216-809-11 METAL CHIP 100 5% 1/10W R257 1-216-809-11 METAL CHIP 100 5% 1/10W R259 1-216-809-11 METAL CHIP 100 5% 1/10W R260 1-216-821-11 METAL CHIP 1K 5% 1/10W R265 1-216-813-11 METAL CHIP 220 5% 1/10W R266 1-216-813-11 METAL CHIP 220 5% 1/10W R271 1-216-833-11 METAL CHIP 10K 5% 1/10W R272 1-216-821-11 METAL CHIP 1K 5% 1/10W R275 1-216-833-11 METAL CHIP 10K 5% 1/10W R276 1-216-809-11 METAL CHIP 100 5% 1/10W R277 1-216-864-11 METAL CHIP 0 5% 1/10W R279 1-216-809-11 METAL CHIP 100 5% 1/10W R280 1-216-296-11 SHORT CHIP 0 < SWITCH > S101 1-771-853-11 SWITCH, DETECTION (LIMIT) < VIBRATOR > X201 1-767-408-21 VIBRATOR, CRYSTAL (16.9MHz) ************************************************************* 1-686-936-11 CD SWITCH BOARD **************** < DIODE > D748 8-719-058-04 DIODE SEL5223S-TP15 (=/1) < TRANSISTOR > Q748 8-729-116-02 TRANSISTOR BA1A4M-TP < RESISTOR > R748 1-249-411-11 CARBON 330 5% 1/4W R749 1-249-410-11 CARBON 270 5% 1/4W F R788 1-249-427-11 CARBON 6.8K 5% 1/4W F R789 1-249-429-11 CARBON 10K 5% 1/4W R790 1-249-431-11 CARBON 15K 5% 1/4W R791 1-249-433-11 CARBON 22K 5% 1/4W R792 1-249-435-11 CARBON 33K 5% 1/4W < SWITCH > S749 1-762-875-21 SWITCH, KEYBOARD (=/1) S788 1-762-875-21 SWITCH, KEYBOARD (Z,OPEN/CLOSE) S789 1-762-875-21 SWITCH, KEYBOARD (EX-CHANGE/DISK SKIP) S790 1-762-875-21 SWITCH, KEYBOARD (DISC 3) S791 1-762-875-21 SWITCH, KEYBOARD (DISC 2) S792 1-762-875-21 SWITCH, KEYBOARD (DISC 1) ************************************************************* A-4731-330-A DISPLAY BOARD, COMPLETE ************************ 4-231-581-01 HOLDER (FL) < CAPACITOR > C100 1-126-964-11 ELECT 10uF 20% 50V C101 1-137-194-81 FILM 0.47uF 5% 50V C102 1-137-194-81 FILM 0.47uF 5% 50V C104 1-126-964-11 ELECT 10uF 20% 50V CD SWITCH www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 61 Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks HCD-GN600 C105 1-126-957-11 ELECT 0.22uF 20% 50V C106 1-136-165-00 FILM 0.1uF 5% 50V C107 1-136-165-00 FILM 0.1uF 5% 50V C109 1-124-261-00 ELECT 10uF 20% 50V C110 1-126-957-11 ELECT 0.22uF 20% 50V C111 1-136-157-00 FILM 0.022uF 5% 50V C112 1-136-157-00 FILM 0.022uF 5% 50V C114 1-126-964-11 ELECT 10uF 20% 50V C115 1-126-957-11 ELECT 0.22uF 20% 50V C116 1-137-367-11 MYLAR 0.0033uF 5% 50V C117 1-137-367-11 MYLAR 0.0033uF 5% 50V C118 1-126-964-11 ELECT 10uF 20% 50V C119 1-124-261-00 ELECT 10uF 20% 50V C120 1-126-957-11 ELECT 0.22uF 20% 50V C121 1-126-963-11 ELECT 4.7uF 20% 50V C122 1-124-584-00 ELECT 100uF 20% 10V C123 1-104-665-11 ELECT 100uF 20% 10V C124 1-126-964-11 ELECT 10uF 20% 50V C125 1-164-159-11 CERAMIC 0.1uF 50V C152 1-162-286-31 CERAMIC 220PF 10% 50V C153 1-162-286-31 CERAMIC 220PF 10% 50V C154 1-162-286-31 CERAMIC 220PF 10% 50V C155 1-162-286-31 CERAMIC 220PF 10% 50V C156 1-162-286-31 CERAMIC 220PF 10% 50V C157 1-162-286-31 CERAMIC 220PF 10% 50V C618 1-162-306-11 CERAMIC 0.01uF 30% 16V C619 1-124-589-11 ELECT 47uF 20% 16V C620 1-162-306-11 CERAMIC 0.01uF 30% 16V C622 1-126-163-11 ELECT 4.7uF 20% 50V C623 1-162-294-31 CERAMIC 0.001uF 10% 50V C624 1-162-306-11 CERAMIC 0.01uF 30% 16V C625 1-162-306-11 CERAMIC 0.01uF 30% 16V C626 1-162-306-11 CERAMIC 0.01uF 30% 16V C627 1-162-306-11 CERAMIC 0.01uF 30% 16V C628 1-162-306-11 CERAMIC 0.01uF 30% 16V C651 1-164-159-11 CERAMIC 0.1uF 50V C652 1-124-261-00 ELECT 10uF 20% 50V C653 1-124-261-00 ELECT 10uF 20% 50V C710 1-162-306-11 CERAMIC 0.01uF 30% 16V C711 1-162-306-11 CERAMIC 0.01uF 30% 16V C712 1-162-306-11 CERAMIC 0.01uF 30% 16V < CONNECTOR > * CN601 1-569-935-11 SOCKET, CONNECTOR 19P CN604 1-568-860-11 SOCKET, CONNECTOR 17P < DIODE > D100 8-719-983-63 DIODE MTZJ-T-72-3.3B D101 8-719-991-33 DIODE 1SS133T-72 D102 8-719-991-33 DIODE 1SS133T-72 D103 8-719-991-33 DIODE 1SS133T-72 D104 8-719-991-33 DIODE 1SS133T-72 D105 8-719-991-33 DIODE 1SS133T-72 D106 6-500-522-11 DIODE 10EDB40-TA2B5 D107 6-500-522-11 DIODE 10EDB40-TA2B5 D601 8-719-063-93 DIODE SLR325VC-N-T32 (REC PAUSE/START) D602 8-719-057-97 DIODE SEL5923A-TP15 (GAME) D603 8-719-057-97 DIODE SEL5923A-TP15 (MD(VIDEO)) D604 8-719-057-97 DIODE SEL5923A-TP15 (CD) D605 8-719-057-97 DIODE SEL5923A-TP15 (TUNER/BAND) D606 8-719-057-97 DIODE SEL5923A-TP15 (TAPE A/B) D610 8-719-109-85 DIODE MTZJ-T-72-5.1B < FLUORESCENT INDICATOR TUBE > FL601 1-518-862-11 INDICATOR TUBE, FLUORESCENT < IC > IC101 8-759-167-88 IC NJM4565D IC102 8-759-167-88 IC NJM4565D IC601 6-802-534-01 IC MB90M407PF-G-124-BND < TRANSISTOR > Q100 8-729-141-30 TRANSISTOR 2SC3623ATP-LK Q601 8-729-116-02 TRANSISTOR BA1A4M-TP Q602 8-729-116-02 TRANSISTOR BA1A4M-TP Q603 8-729-116-02 TRANSISTOR BA1A4M-TP Q604 8-729-116-02 TRANSISTOR BA1A4M-TP Q605 8-729-140-04 TRANSISTOR 2SB1116-TP-LK Q606 8-729-140-04 TRANSISTOR 2SB1116-TP-LK Q707 8-729-116-02 TRANSISTOR BA1A4M-TP Q807 8-729-029-94 TRANSISTOR BA1L3Z-TP Q808 8-729-029-94 TRANSISTOR BA1L3Z-TP < RESISTOR > R102 1-249-419-11 CARBON 1.5K 5% 1/4W F R103 1-249-419-11 CARBON 1.5K 5% 1/4W F R104 1-249-437-11 CARBON 47K 5% 1/4W R105 1-249-415-11 CARBON 680 5% 1/4W F R106 1-249-441-11 CARBON 100K 5% 1/4W R107 1-249-441-11 CARBON 100K 5% 1/4W R108 1-249-419-11 CARBON 1.5K 5% 1/4W F R109 1-249-419-11 CARBON 1.5K 5% 1/4W F R110 1-249-437-11 CARBON 47K 5% 1/4W R111 1-249-415-11 CARBON 680 5% 1/4W F R112 1-249-441-11 CARBON 100K 5% 1/4W R113 1-249-441-11 CARBON 100K 5% 1/4W R114 1-249-419-11 CARBON 1.5K 5% 1/4W F R115 1-249-419-11 CARBON 1.5K 5% 1/4W F R116 1-249-437-11 CARBON 47K 5% 1/4W R117 1-249-415-11 CARBON 680 5% 1/4W F R118 1-249-441-11 CARBON 100K 5% 1/4W R119 1-249-441-11 CARBON 100K 5% 1/4W R120 1-249-419-11 CARBON 1.5K 5% 1/4W F R121 1-249-419-11 CARBON 1.5K 5% 1/4W F R122 1-249-437-11 CARBON 47K 5% 1/4W R123 1-249-415-11 CARBON 680 5% 1/4W F R124 1-249-441-11 CARBON 100K 5% 1/4W R125 1-249-441-11 CARBON 100K 5% 1/4W R127 1-249-409-11 CARBON 220 5% 1/4W F R128 1-247-895-00 CARBON 470K 5% 1/4W R129 1-249-425-11 CARBON 4.7K 5% 1/4W F R130 1-249-425-11 CARBON 4.7K 5% 1/4W F R131 1-249-441-11 CARBON 100K 5% 1/4W R132 1-249-441-11 CARBON 100K 5% 1/4W R133 1-249-441-11 CARBON 100K 5% 1/4W R134 1-249-441-11 CARBON 100K 5% 1/4W R136 1-249-439-11 CARBON 68K 5% 1/4W R137 1-249-433-11 CARBON 22K 5% 1/4W R138 1-249-417-11 CARBON 1K 5% 1/4W F DISPLAY www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 62 Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks HCD-GN600 R139 1-249-411-11 CARBON 330 5% 1/4W R140 1-247-807-31 CARBON 100 5% 1/4W R626 1-249-411-11 CARBON 330 5% 1/4W R627 1-249-411-11 CARBON 330 5% 1/4W R628 1-249-411-11 CARBON 330 5% 1/4W R629 1-249-411-11 CARBON 330 5% 1/4W R630 1-249-411-11 CARBON 330 5% 1/4W R631 1-249-415-11 CARBON 680 5% 1/4W F R632 1-249-415-11 CARBON 680 5% 1/4W F R633 1-249-415-11 CARBON 680 5% 1/4W F R634 1-249-429-11 CARBON 10K 5% 1/4W R635 1-249-429-11 CARBON 10K 5% 1/4W R636 1-249-429-11 CARBON 10K 5% 1/4W R637 1-249-429-11 CARBON 10K 5% 1/4W R645 1-249-429-11 CARBON 10K 5% 1/4W R646 1-247-807-31 CARBON 100 5% 1/4W R647 1-247-807-31 CARBON 100 5% 1/4W R652 1-249-429-11 CARBON 10K 5% 1/4W R653 1-249-429-11 CARBON 10K 5% 1/4W R654 1-247-807-31 CARBON 100 5% 1/4W R655 1-247-807-31 CARBON 100 5% 1/4W R656 1-247-807-31 CARBON 100 5% 1/4W R657 1-249-431-11 CARBON 15K 5% 1/4W R658 1-249-431-11 CARBON 15K 5% 1/4W R659 1-249-431-11 CARBON 15K 5% 1/4W R660 1-247-903-00 CARBON 1M 5% 1/4W R661 1-249-429-11 CARBON 10K 5% 1/4W R662 1-249-429-11 CARBON 10K 5% 1/4W R663 1-249-429-11 CARBON 10K 5% 1/4W R751 1-249-413-11 CARBON 470 5% 1/4W F R752 1-249-415-11 CARBON 680 5% 1/4W F R753 1-249-417-11 CARBON 1K 5% 1/4W F R754 1-249-419-11 CARBON 1.5K 5% 1/4W F R755 1-249-419-11 CARBON 1.5K 5% 1/4W F R756 1-249-421-11 CARBON 2.2K 5% 1/4W F R757 1-247-843-11 CARBON 3.3K 5% 1/4W R758 1-249-425-11 CARBON 4.7K 5% 1/4W F R779 1-249-413-11 CARBON 470 5% 1/4W F R781 1-249-415-11 CARBON 680 5% 1/4W F R782 1-249-417-11 CARBON 1K 5% 1/4W F R783 1-249-419-11 CARBON 1.5K 5% 1/4W F R784 1-249-419-11 CARBON 1.5K 5% 1/4W F R785 1-249-421-11 CARBON 2.2K 5% 1/4W F R786 1-247-843-11 CARBON 3.3K 5% 1/4W R787 1-249-425-11 CARBON 4.7K 5% 1/4W F R807 1-249-441-11 CARBON 100K 5% 1/4W R808 1-249-441-11 CARBON 100K 5% 1/4W R817 1-249-406-11 CARBON 120 5% 1/4W F R818 1-249-408-11 CARBON 180 5% 1/4W F R819 1-249-408-11 CARBON 180 5% 1/4W F R820 1-249-408-11 CARBON 180 5% 1/4W F R821 1-249-406-11 CARBON 120 5% 1/4W F R822 1-249-417-11 CARBON 1K 5% 1/4W F R823 1-249-417-11 CARBON 1K 5% 1/4W F < SWITCH > S751 1-762-875-21 SWITCH, KEYBOARD (gG) S752 1-762-875-21 SWITCH, KEYBOARD (x) S753 1-762-875-21 SWITCH, KEYBOARD (X) S754 1-762-875-21 SWITCH, KEYBOARD (-,.) S755 1-762-875-21 SWITCH, KEYBOARD (>,+) S756 1-762-875-21 SWITCH, KEYBOARD (M,ALBUM +) S757 1-762-875-21 SWITCH, KEYBOARD (m,ALBUM -) S758 1-762-875-21 SWITCH, KEYBOARD (REC PAUSE/START) S779 1-762-875-21 SWITCH, KEYBOARD (CD SYNC) S782 1-762-875-21 SWITCH, KEYBOARD (GAME MIXING) S783 1-762-875-21 SWITCH, KEYBOARD (GAME) S784 1-762-875-21 SWITCH, KEYBOARD (MD(VIDEO)) S785 1-762-875-21 SWITCH, KEYBOARD (TAPE A/B) S786 1-762-875-21 SWITCH, KEYBOARD (TUNER/BAND) S787 1-762-875-21 SWITCH, KEYBOARD (CD) < VIBRATOR > X601 1-781-282-51 VIBRATOR, CERAMIC (4MHz) ************************************************************* 1-687-135-11 DRIVER BOARD ************* < CAPACITOR > C715 1-126-933-11 ELECT 100uF 20% 16V C731 1-126-964-51 ELECT 10uF 20% 50V C735 1-164-159-11 CERAMIC 0.1uF 50V C736 1-164-159-11 CERAMIC 0.1uF 50V C737 1-164-159-11 CERAMIC 0.1uF 50V C741 1-162-306-11 CERAMIC 0.01uF 30% 16V C751 1-162-306-11 CERAMIC 0.01uF 30% 16V C752 1-164-159-11 CERAMIC 0.1uF 50V < CONNECTOR > CN701 1-785-338-11 PIN, CONNECTOR(LIGHT ANGLE)12P CN702 1-784-766-11 CONNECTOR, FFC 5P * CN703 1-564-720-11 PIN, CONNECTOR (SMALL TYPE) 4P CN704 1-785-328-11 PIN, CONNECTOR (LIGHT ANGRE)2P < DIODE > D701 8-719-947-16 DIODE MTZJ-T-72-5.1A D711 8-719-983-66 DIODE MTZJ-T-72-3.6B < IC > IC701 8-759-598-69 IC BA6956AN IC712 8-759-598-69 IC BA6956AN < TRANSISTOR > Q731 8-729-029-66 TRANSISTOR DTC114ESA-TP < RESISTOR > R701 1-249-413-11 CARBON 470 5% 1/4W F R702 1-247-807-31 CARBON 100 5% 1/4W R711 1-249-417-11 CARBON 1K 5% 1/4W F R712 1-249-425-11 CARBON 4.7K 5% 1/4W F R713 1-249-433-11 CARBON 22K 5% 1/4W R721 1-249-425-11 CARBON 4.7K 5% 1/4W F R722 1-249-425-11 CARBON 4.7K 5% 1/4W F R723 1-249-425-11 CARBON 4.7K 5% 1/4W F R731 1-247-807-31 CARBON 100 5% 1/4W R732 1-249-425-11 CARBON 4.7K 5% 1/4W F R733 1-249-417-11 CARBON 1K 5% 1/4W F R734 1-249-433-11 CARBON 22K 5% 1/4W R735 1-247-807-31 CARBON 100 5% 1/4W R751 1-249-425-11 CARBON 4.7K 5% 1/4W F ************************************************************* DISPLAY DRIVER www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 63 Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks HCD-GN600 MAIN A-4731-327-A GAME IN BOARD, COMPLETE ************************ < CAPACITOR > C604 1-124-257-00 ELECT 2.2uF 20% 50V C606 1-124-257-00 ELECT 2.2uF 20% 50V C630 1-162-294-31 CERAMIC 0.001uF 10% 50V C631 1-162-294-31 CERAMIC 0.001uF 10% 50V C634 1-162-294-31 CERAMIC 0.001uF 10% 50V C635 1-162-294-31 CERAMIC 0.001uF 10% 50V C715 1-162-215-31 CERAMIC 47PF 5% 50V C716 1-162-215-31 CERAMIC 47PF 5% 50V C717 1-124-584-00 ELECT 100uF 20% 10V C718 1-124-584-00 ELECT 100uF 20% 10V C719 1-124-257-00 ELECT 2.2uF 20% 50V C736 1-124-261-00 ELECT 10uF 20% 50V C737 1-124-261-00 ELECT 10uF 20% 50V C738 1-124-257-00 ELECT 2.2uF 20% 50V C739 1-162-215-31 CERAMIC 47PF 5% 50V C740 1-162-282-31 CERAMIC 100PF 10% 50V C741 1-124-250-11 ELECT 0.15uF 20% 50V C742 1-162-215-31 CERAMIC 47PF 5% 50V C743 1-162-290-31 CERAMIC 470PF 10% 50V C744 1-162-294-31 CERAMIC 0.001uF 10% 50V C747 1-124-257-00 ELECT 2.2uF 20% 50V C748 1-161-494-00 CERAMIC 0.022uF 25V C749 1-164-159-11 CERAMIC 0.1uF 50V < CONNECTOR > * CN606 1-564-724-11 PIN, CONNECTOR (SMALL TYPE) 8P CN607 1-785-328-11 PIN, CONNECTOR (LIGHT ANGRE) 2P < GROUND TERMINAL > EP701 1-537-738-21 TERMINAL, GROUND EP703 1-537-738-21 TERMINAL, GROUND < IC > IC722 8-759-167-88 IC NJM4565D < JACK > J601 1-764-592-11 JACK 3P (GAME INPUT) J631 1-794-702-11 JACK, HEADPHONE (PHONES) J721 1-817-629-11 JACK (LARGE TYPE) (MIC) < TRANSISTOR > Q721 8-729-119-79 TRANSISTOR 2SC2785TP-FEK < RESISTOR > R602 1-249-417-11 CARBON 1K 5% 1/4W F R603 1-249-417-11 CARBON 1K 5% 1/4W F R604 1-249-441-11 CARBON 100K 5% 1/4W R605 1-249-441-11 CARBON 100K 5% 1/4W R721 1-249-429-11 CARBON 10K 5% 1/4W R722 1-249-432-11 CARBON 18K 5% 1/4W R734 1-247-807-31 CARBON 100 5% 1/4W R735 1-247-885-00 CARBON 180K 5% 1/4W R736 1-249-429-11 CARBON 10K 5% 1/4W R737 1-249-433-11 CARBON 22K 5% 1/4W R738 1-249-417-11 CARBON 1K 5% 1/4W F R739 1-249-441-11 CARBON 100K 5% 1/4W R740 1-249-421-11 CARBON 2.2K 5% 1/4W F R742 1-249-417-11 CARBON 1K 5% 1/4W F R743 1-249-429-11 CARBON 10K 5% 1/4W R744 1-249-441-11 CARBON 100K 5% 1/4W R745 1-247-807-31 CARBON 100 5% 1/4W R746 1-249-417-11 CARBON 1K 5% 1/4W F < VARIABLE RESISTOR > RV722 1-227-452-11 RES, VAR, CARBON 50K (MIC LEVEL) ************************************************************* A-4731-339-A MAIN BOARD, COMPLETE ********************* 7-685-647-79 SCREW +BVTP 3X10 TYPE2 N-S < CAPACITOR > C101 1-126-933-11 ELECT 100uF 20% 16V C102 1-126-964-11 ELECT 10uF 20% 50V C103 1-126-964-11 ELECT 10uF 20% 50V C104 1-126-964-11 ELECT 10uF 20% 50V C105 1-126-795-11 ELECT 10uF 20% 50V C106 1-136-157-00 FILM 0.022uF 5% 50V C107 1-136-157-00 FILM 0.022uF 5% 50V C108 1-136-159-00 FILM 0.033uF 5% 50V C109 1-115-871-11 ELECT 1uF 20% 50V C110 1-137-150-11 MYLAR 0.01uF 5% 100V C111 1-126-795-11 ELECT 10uF 20% 50V C112 1-136-169-00 FILM 0.22uF 5% 50V C113 1-136-171-00 FILM 0.33uF 5% 50V C114 1-126-964-11 ELECT 10uF 20% 50V C115 1-164-156-11 CERAMIC CHIP 0.1uF 25V C116 1-126-933-11 ELECT 100uF 20% 16V C117 1-126-961-11 ELECT 2.2uF 20% 50V C130 1-126-964-11 ELECT 10uF 20% 50V C121 1-162-960-11 CERAMIC CHIP 220PF 10% 50V C122 1-162-960-11 CERAMIC CHIP 220PF 10% 50V C131 1-126-959-11 ELECT 0.47uF 20% 50V C132 1-164-156-11 CERAMIC CHIP 0.1uF 25V C140 1-136-495-11 FILM 0.068uF 5% 50V C150 1-126-964-11 ELECT 10uF 20% 50V C152 1-126-964-11 ELECT 10uF 20% 50V C153 1-126-964-11 ELECT 10uF 20% 50V C154 1-126-964-11 ELECT 10uF 20% 50V C155 1-126-964-11 ELECT 10uF 20% 50V C156 1-136-157-00 FILM 0.022uF 5% 50V C157 1-136-157-00 FILM 0.022uF 5% 50V C158 1-136-159-00 FILM 0.033uF 5% 50V C159 1-115-871-11 ELECT 1uF 20% 50V C160 1-137-150-11 MYLAR 0.01uF 5% 100V C161 1-126-795-11 ELECT 10uF 20% 50V C162 1-136-169-00 FILM 0.22uF 5% 50V C163 1-136-171-00 FILM 0.33uF 5% 50V C167 1-126-961-11 ELECT 2.2uF 20% 50V C200 1-164-156-11 CERAMIC CHIP 0.1uF 25V C201 1-104-665-11 ELECT 100uF 20% 10V C206 1-164-156-11 CERAMIC CHIP 0.1uF 25V GAME IN www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 64 Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks HCD-GN600 MAIN C207 1-126-916-11 ELECT 1000uF 20% 6.3V C209 1-126-928-11 ELECT 3300uF 20% 10V C210 1-164-156-11 CERAMIC CHIP 0.1uF 25V C211 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V C219 1-126-964-11 ELECT 10uF 20% 50V C269 1-126-964-11 ELECT 10uF 20% 50V C286 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V C301 1-130-483-00 MYLAR 0.01uF 5% 50V C303 1-136-165-00 FILM 0.1uF 5% 50V C304 1-126-964-11 ELECT 10uF 20% 50V C305 1-126-960-11 ELECT 1uF 20% 50V C306 1-126-961-11 ELECT 2.2uF 20% 50V C307 1-126-964-11 ELECT 10uF 20% 50V C308 1-126-935-11 ELECT 470uF 20% 16V C309 1-126-947-11 ELECT 47uF 20% 16V C310 1-126-964-11 ELECT 10uF 20% 50V C311 1-126-964-11 ELECT 10uF 20% 50V C312 1-126-964-11 ELECT 10uF 20% 50V C314 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V C315 1-126-960-11 ELECT 1uF 20% 50V C316 1-126-960-11 ELECT 1uF 20% 50V C321 1-164-392-11 CERAMIC CHIP 390PF 10% 50V C326 1-164-392-11 CERAMIC CHIP 390PF 10% 50V C331 1-130-483-00 MYLAR 0.01uF 5% 50V C332 1-137-427-11 MYLAR 120PF 5% 50V C333 1-162-961-11 CERAMIC CHIP 330PF 10% 50V C334 1-162-946-11 CERAMIC CHIP 27PF 5% 50V C335 1-137-150-11 MYLAR 0.01uF 5% 100V C336 1-126-961-11 ELECT 2.2uF 20% 50V C337 1-130-485-00 MYLAR 0.015uF 5% 50V C338 1-130-481-00 MYLAR 0.0068uF 5% 50V C339 1-130-481-00 MYLAR 0.0068uF 5% 50V C340 1-130-486-00 MYLAR 0.018uF 10% 50V C341 1-126-964-11 ELECT 10uF 20% 50V C342 1-126-947-11 ELECT 47uF 20% 16V C351 1-130-483-00 MYLAR 0.01uF 5% 50V C353 1-136-165-00 FILM 0.1uF 5% 50V C354 1-126-964-11 ELECT 10uF 20% 50V C355 1-126-960-11 ELECT 1uF 20% 50V C356 1-126-961-11 ELECT 2.2uF 20% 50V C359 1-126-947-11 ELECT 47uF 20% 16V C361 1-126-964-11 ELECT 10uF 20% 50V C364 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V C365 1-126-960-11 ELECT 1uF 20% 50V C371 1-164-392-11 CERAMIC CHIP 390PF 10% 50V C376 1-164-392-11 CERAMIC CHIP 390PF 10% 50V C381 1-130-483-00 MYLAR 0.01uF 5% 50V C382 1-137-427-11 MYLAR 120PF 5% 50V C383 1-162-961-11 CERAMIC CHIP 330PF 10% 50V C384 1-162-946-11 CERAMIC CHIP 27PF 5% 50V C385 1-126-964-11 ELECT 10uF 20% 50V C386 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V C387 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V C390 1-126-935-11 ELECT 470uF 20% 10V C391 1-126-933-11 ELECT 100uF 20% 16V C395 1-162-919-11 CERAMIC CHIP 22PF 5% 50V C396 1-126-965-91 ELECT 22uF 20% 50V C397 1-126-964-11 ELECT 10uF 20% 50V C398 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C399 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C416 1-164-156-11 CERAMIC CHIP 0.1uF 25V C427 1-162-923-11 CERAMIC CHIP 47PF 5% 50V C432 1-162-923-11 CERAMIC CHIP 47PF 5% 50V C433 1-162-923-11 CERAMIC CHIP 47PF 5% 50V C434 1-162-923-11 CERAMIC CHIP 47PF 5% 50V C498 1-164-156-11 CERAMIC CHIP 0.1uF 25V C502 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V C503 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V C510 1-162-919-11 CERAMIC CHIP 22PF 5% 50V C511 1-162-917-11 CERAMIC CHIP 15PF 5% 50V C512 1-164-156-11 CERAMIC CHIP 0.1uF 25V C516 1-126-916-11 ELECT 1000uF 20% 6.3V C562 1-104-665-11 ELECT 100uF 20% 10V C564 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C596 1-164-156-11 CERAMIC CHIP 0.1uF 25V C598 1-126-964-11 ELECT 10uF 20% 50V C601 1-126-964-11 ELECT 10uF 20% 50V C602 1-136-165-00 FILM 0.1uF 5% 50V C603 1-136-165-00 FILM 0.1uF 5% 50V C620 1-126-963-11 ELECT 4.7uF 20% 50V C621 1-107-721-11 ELECT 4.7uF 20% 100V C650 1-109-889-11 ELECT 1uF 20% 50V C651 1-107-717-11 ELECT 47uF 20% 50V C656 1-125-891-11 CERAMIC CHIP 0.47uF 10% 25V C670 1-126-963-11 ELECT 4.7uF 20% 50V C671 1-107-721-11 ELECT 4.7uF 20% 100V C851 1-164-156-11 CERAMIC CHIP 0.1uF 25V C901 1-126-944-11 ELECT 3300uF 20% 25V C902 1-126-943-61 ELECT 2200uF 20% 25V C903 1-126-768-11 ELECT 2200uF 20% 16V C904 1-130-483-00 MYLAR 0.01uF 5% 50V C905 1-130-483-00 MYLAR 0.01uF 5% 50V C906 1-126-933-11 ELECT 100uF 20% 16V C908 1-136-165-00 FILM 0.1uF 5% 50V C909 1-136-165-00 FILM 0.1uF 5% 50V C910 1-164-156-11 CERAMIC CHIP 0.1uF 25V C911 1-126-935-11 ELECT 470uF 20% 16V C912 1-164-156-11 CERAMIC CHIP 0.1uF 25V C913 1-126-935-11 ELECT 470uF 20% 16V C914 1-126-935-11 ELECT 470uF 20% 16V C915 1-164-156-11 CERAMIC CHIP 0.1uF 25V C917 1-126-935-11 ELECT 470uF 20% 10V C918 1-164-156-11 CERAMIC CHIP 0.1uF 25V C919 1-104-656-11 ELECT 2200uF 20% 6.3V C920 1-126-964-11 ELECT 10uF 20% 50V C921 1-126-968-11 ELECT 100uF 20% 50V C922 1-126-961-11 ELECT 2.2uF 20% 50V C923 1-126-961-11 ELECT 2.2uF 20% 50V C924 1-164-156-11 CERAMIC CHIP 0.1uF 25V < CONNECTOR > CN201 1-779-299-11 CONNECTOR,FFC(LIF(NON-ZIF))31P * CN301 1-568-449-11 HOUSING, CONNECTOR(PC BOARD)3P * CN304 1-569-930-11 SOCKET, CONNECTOR 13P * CN402 1-569-935-11 SOCKET, CONNECTOR 19P CN501 1-785-330-11 PIN, CONNECTOR (LIGHT ANGLE)4P CN502 1-785-336-11 PIN, CONNECTOR(LIGHT ANGLE)10P CN702 1-569-906-11 SOCKET, CONNECTOR 11P CN851 1-564-506-11 PLUG, CONNECTOR 3P CN901 1-770-726-11 CONNECTOR, BOARD TO BOARD 6P www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 65 Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks HCD-GN600 MAIN CN902 1-778-982-11 CONNECTOR, BOARD TO BOARD 13P < DIODE > D130 8-719-988-61 DIODE 1SS355TE-17 D392 8-719-988-61 DIODE 1SS355TE-17 D393 8-719-988-61 DIODE 1SS355TE-17 D394 8-719-988-61 DIODE 1SS355TE-17 D501 8-719-988-61 DIODE 1SS355TE-17 D502 8-719-988-61 DIODE 1SS355TE-17 D503 8-719-988-61 DIODE 1SS355TE-17 D504 8-719-988-61 DIODE 1SS355TE-17 D505 8-719-988-61 DIODE 1SS355TE-17 D508 8-719-988-61 DIODE 1SS355TE-17 D509 8-719-988-61 DIODE 1SS355TE-17 D601 8-719-988-61 DIODE 1SS355TE-17 D602 8-719-988-61 DIODE 1SS355TE-17 D603 8-719-988-61 DIODE 1SS355TE-17 D901 8-719-028-23 DIODE D3SBA20-4101 D909 6-500-522-21 DIODE 10EDB40-TB3 D910 6-500-522-21 DIODE 10EDB40-TB3 D911 6-500-522-21 DIODE 10EDB40-TB3 D912 6-500-522-21 DIODE 10EDB40-TB3 D913 6-500-522-21 DIODE 10EDB40-TB3 D914 6-500-522-21 DIODE 10EDB40-TB3 D915 6-500-522-21 DIODE 10EDB40-TB3 D917 8-719-988-61 DIODE 1SS355TE-17 D941 8-719-977-81 DIODE UDZ-TE-17-33B < FERRITE BEAD > FB117 1-216-864-11 METAL CHIP 0 5% 1/10W FB167 1-216-864-11 METAL CHIP 0 5% 1/10W FB201 1-419-152-11 FERRITE 0uH FB202 1-216-864-11 METAL CHIP 0 5% 1/10W FB203 1-216-864-11 METAL CHIP 0 5% 1/10W FB204 1-216-864-11 METAL CHIP 0 5% 1/10W FB205 1-216-864-11 METAL CHIP 0 5% 1/10W FB284 1-216-864-11 METAL CHIP 0 5% 1/10W FB286 1-216-864-11 METAL CHIP 0 5% 1/10W FB516 1-414-772-11 FERRITE 0uH FB562 1-414-772-11 FERRITE 0uH < IC > IC102 6-703-650-11 IC M61529FP-D60G IC201 8-749-019-25 IC TOTX141 (CD DIGITAL OUT) IC301 6-702-130-01 IC HA12237F IC302 8-759-508-69 IC BA3126N IC303 8-759-710-97 IC NJM4565M(TE2) IC501 6-802-545-01 IC M30622MGN-B09FP IC502 6-703-610-01 IC RT8H015C-T112-1 IC601 8-759-533-04 IC M62703ML-E1 IC901 8-759-701-59 IC TA7809S IC902 8-759-701-59 IC TA7809S IC903 6-703-546-01 IC TA7804LS IC904 6-702-771-01 IC TA78033LS < JACK > J117 1-764-767-21 JACK, PIN 2P (MD/VIDEO(AUDIO) IN) J716 1-774-227-11 JACK, PIN 1PP (VIDEO OUT) < JUMPER RESISTOR > JR001 1-216-296-11 SHORT CHIP 0 JR003 1-216-864-11 METAL CHIP 0 5% 1/10W JR005 1-216-864-11 METAL CHIP 0 5% 1/10W JR006 1-216-296-11 SHORT CHIP 0 JR007 1-216-296-11 SHORT CHIP 0 JR008 1-216-864-11 METAL CHIP 0 5% 1/10W JR009 1-216-864-11 METAL CHIP 0 5% 1/10W JR011 1-216-296-11 SHORT CHIP 0 JR012 1-216-296-11 SHORT CHIP 0 JR013 1-216-864-11 METAL CHIP 0 5% 1/10W JR015 1-216-864-11 METAL CHIP 0 5% 1/10W JR016 1-216-864-11 METAL CHIP 0 5% 1/10W JR017 1-216-864-11 METAL CHIP 0 5% 1/10W JR018 1-216-864-11 METAL CHIP 0 5% 1/10W JR022 1-216-864-11 METAL CHIP 0 5% 1/10W JR024 1-216-864-11 METAL CHIP 0 5% 1/10W JR026 1-4414-760-21 FERRITE 0uH JR045 1-216-296-11 SHORT CHIP 0 JR103 1-216-864-11 METAL CHIP 0 5% 1/10W JR104 1-216-296-11 SHORT CHIP 0 JR118 1-216-296-11 SHORT CHIP 0 JR130 1-216-864-11 METAL CHIP 0 5% 1/10W JR138 1-216-864-11 METAL CHIP 0 5% 1/10W JR390 1-216-864-11 METAL CHIP 0 5% 1/10W < COIL > L301 1-410-780-11 INDUCTOR 27mH L302 1-414-189-31 INDUCTOR 100uH L351 1-410-780-11 INDUCTOR 27mH < TRANSISTOR > Q101 8-729-120-28 TRANSISTOR 2SC1623-T1-L5L6 Q151 8-729-120-28 TRANSISTOR 2SC1623-T1-L5L6 Q201 8-729-802-80 TRANSISTOR 2SC3661-TB Q206 8-729-900-53 TRANSISTOR DTC114EKA-T146 Q207 8-729-027-31 TRANSISTOR DTA124EKA-T146 Q251 8-729-802-80 TRANSISTOR 2SC3661-TB Q301 8-729-141-73 TRANSISTOR 2SC3624A-T1L15L16 Q302 8-729-142-46 TRANSISTOR 2SC2001TP-LK Q303 8-729-142-46 TRANSISTOR 2SC2001TP-LK Q304 8-729-027-31 TRANSISTOR DTA124EKA-T146 Q305 8-729-900-53 TRANSISTOR DTC114EKA-T146 Q306 8-729-900-53 TRANSISTOR DTC114EKA-T146 Q307 8-729-216-22 TRANSISTOR 2SA812-T1-M5M6 Q310 8-729-900-53 TRANSISTOR DTC114EKA-T146 Q389 8-729-900-53 TRANSISTOR DTC114EKA-T146 Q390 8-729-900-53 TRANSISTOR DTC114EKA-T146 Q391 8-729-140-04 TRANSISTOR 2SB1116-TP-LK Q392 8-729-900-53 TRANSISTOR DTC114EKA-T146 Q393 8-729-116-57 TRANSISTOR 2SB1068TP-K Q394 8-729-900-53 TRANSISTOR DTC114EKA-T146 Q395 8-729-900-53 TRANSISTOR DTC114EKA-T146 Q396 8-729-140-04 TRANSISTOR 2SB1116-TP-LK Q398 8-729-900-53 TRANSISTOR DTC114EKA-T146 Q399 8-729-141-73 TRANSISTOR 2SC3624A-T1L15L16 Q601 8-729-120-28 TRANSISTOR 2SC1623-T1-L5L6 Q602 8-729-014-97 TRANSISTOR FA1L3Z-T1B Q620 8-729-802-80 TRANSISTOR 2SC3661-TB www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 66 Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks HCD-GN600 MAIN Q621 8-729-802-80 TRANSISTOR 2SC3661-TB Q650 8-729-027-31 TRANSISTOR DTA124EKA-T146 Q651 8-729-900-53 TRANSISTOR DTC114EKA-T146 Q652 8-729-027-31 TRANSISTOR DTA124EKA-T146 Q670 8-729-802-80 TRANSISTOR 2SC3661-TB Q671 8-729-802-80 TRANSISTOR 2SC3661-TB Q851 8-729-140-04 TRANSISTOR 2SB1116-TP-LK Q852 8-729-620-05 TRANSISTOR 2SC2603TP-EF Q901 8-729-040-20 TRANSISTOR RT1P137L-TP Q902 8-729-900-53 TRANSISTOR DTC114EKA-T146 Q903 8-729-209-60 TRANSISTOR 2SB1375 < RESISTOR > R101 1-216-825-11 METAL CHIP 2.2K 5% 1/10W R102 1-216-833-11 METAL CHIP 10K 5% 1/10W R103 1-220-373-11 METAL CHIP 620 5% 1/10W R104 1-216-821-11 METAL CHIP 1K 5% 1/10W R105 1-216-841-11 METAL CHIP 47K 5% 1/10W R106 1-216-833-11 METAL CHIP 10K 5% 1/10W R107 1-216-809-11 METAL CHIP 100 5% 1/10W R110 1-216-864-11 METAL CHIP 0 5% 1/10W R112 1-216-864-11 METAL CHIP 0 5% 1/10W R117 1-216-845-11 METAL CHIP 100K 5% 1/10W R118 1-216-821-11 METAL CHIP 1K 5% 1/10W R121 1-216-821-11 METAL CHIP 1K 5% 1/10W R122 1-216-821-11 METAL CHIP 1K 5% 1/10W R130 1-216-825-11 METAL CHIP 2.2K 5% 1/10W R131 1-216-825-11 METAL CHIP 2.2K 5% 1/10W R132 1-216-857-11 METAL CHIP 1M 5% 1/10W R133 1-216-845-11 METAL CHIP 100K 5% 1/10W R134 1-218-701-11 METAL CHIP 2.4K 5% 1/10W R140 1-216-833-11 METAL CHIP 10K 5% 1/10W R141 1-216-809-11 METAL CHIP 100 5% 1/10W R142 1-216-809-11 METAL CHIP 100 5% 1/10W R150 1-216-825-11 METAL CHIP 2.2K 5% 1/10W R151 1-216-825-11 METAL CHIP 2.2K 5% 1/10W R152 1-216-833-11 METAL CHIP 10K 5% 1/10W R153 1-220-373-11 METAL CHIP 620 5% 1/10W R154 1-216-821-11 METAL CHIP 1K 5% 1/10W R155 1-216-841-11 METAL CHIP 47K 5% 1/10W R156 1-216-833-11 METAL CHIP 10K 5% 1/10W R157 1-216-809-11 METAL CHIP 100 5% 1/10W R167 1-216-845-11 METAL CHIP 100K 5% 1/10W R168 1-216-821-11 METAL CHIP 1K 5% 1/10W R204 1-216-833-11 METAL CHIP 10K 5% 1/10W R205 1-216-821-11 METAL CHIP 1K 5% 1/10W R206 1-216-839-11 RES CHIP 33K 5% 1/10W R224 1-216-826-11 METAL CHIP 2.7K 5% 1/10W R226 1-216-847-11 METAL CHIP 150K 5% 1/10W R228 1-216-843-11 METAL CHIP 68K 5% 1/10W R254 1-216-833-11 METAL CHIP 10K 5% 1/10W R255 1-216-821-11 METAL CHIP 1K 5% 1/10W R256 1-216-839-11 RES CHIP 33K 5% 1/10W R284 1-216-853-11 METAL CHIP 470K 5% 1/10W R285 1-216-837-11 METAL CHIP 22K 5% 1/10W R286 1-216-837-11 METAL CHIP 22K 5% 1/10W R301 1-216-827-11 METAL CHIP 3.3K 5% 1/10W R302 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R303 1-216-833-11 METAL CHIP 10K 5% 1/10W R304 1-216-825-11 METAL CHIP 2.2K 5% 1/10W R305 1-216-841-11 METAL CHIP 47K 5% 1/10W R306 1-216-837-11 METAL CHIP 22K 5% 1/10W R307 1-216-857-11 METAL CHIP 1M 5% 1/10W R308 1-216-809-11 METAL CHIP 100 5% 1/10W R309 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R310 1-216-809-11 METAL CHIP 100 5% 1/10W R312 1-216-809-11 METAL CHIP 100 5% 1/10W R313 1-216-821-11 METAL CHIP 1K 5% 1/10W R314 1-216-821-11 METAL CHIP 1K 5% 1/10W R315 1-216-833-11 METAL CHIP 10K 5% 1/10W R316 1-216-833-11 METAL CHIP 10K 5% 1/10W R317 1-216-833-11 METAL CHIP 10K 5% 1/10W R320 1-216-825-11 METAL CHIP 2.2K 5% 1/10W R327 1-216-835-11 METAL CHIP 15K 5% 1/10W R328 1-216-827-11 METAL CHIP 3.3K 5% 1/10W R329 1-216-833-11 METAL CHIP 10K 5% 1/10W R330 1-216-837-11 METAL CHIP 22K 5% 1/10W R332 1-216-832-11 METAL CHIP 8.2K 5% 1/10W R333 1-216-825-11 METAL CHIP 2.2K 5% 1/10W R334 1-216-845-11 METAL CHIP 100K 5% 1/10W R342 1-216-825-11 METAL CHIP 2.2K 5% 1/10W 0R343 1-219-787-17 FUSIBLE 5.6 5% 1/4W 0R344 1-219-787-17 FUSIBLE 5.6 5% 1/4W R345 1-216-836-11 METAL CHIP 18K 5% 1/10W R346 1-216-836-11 METAL CHIP 18K 5% 1/10W R347 1-216-830-11 METAL CHIP 5.6K 5% 1/10W R351 1-216-827-11 METAL CHIP 3.3K 5% 1/10W R352 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R353 1-216-833-11 METAL CHIP 10K 5% 1/10W R354 1-216-825-11 METAL CHIP 2.2K 5% 1/10W R355 1-216-841-11 METAL CHIP 47K 5% 1/10W R360 1-216-819-11 METAL CHIP 680 5% 1/10W R361 1-216-825-11 METAL CHIP 2.2K 5% 1/10W R362 1-216-833-11 METAL CHIP 10K 5% 1/10W R363 1-216-825-11 METAL CHIP 2.2K 5% 1/10W R364 1-216-819-11 METAL CHIP 680 5% 1/10W R365 1-216-833-11 METAL CHIP 10K 5% 1/10W R366 1-216-819-11 METAL CHIP 680 5% 1/10W R367 1-216-833-11 METAL CHIP 10K 5% 1/10W R368 1-216-833-11 METAL CHIP 10K 5% 1/10W R369 1-216-833-11 METAL CHIP 10K 5% 1/10W R370 1-216-825-11 METAL CHIP 2.2K 5% 1/10W R371 1-216-827-11 METAL CHIP 3.3K 5% 1/10W R372 1-216-825-11 METAL CHIP 2.2K 5% 1/10W R373 1-216-825-11 METAL CHIP 2.2K 5% 1/10W R374 1-216-833-11 METAL CHIP 10K 5% 1/10W R375 1-216-833-11 METAL CHIP 10K 5% 1/10W R376 1-216-833-11 METAL CHIP 10K 5% 1/10W R377 1-216-833-11 METAL CHIP 10K 5% 1/10W R378 1-216-833-11 METAL CHIP 10K 5% 1/10W R379 1-216-833-11 METAL CHIP 10K 5% 1/10W R380 1-216-837-11 METAL CHIP 22K 5% 1/10W R382 1-216-832-11 METAL CHIP 8.2K 5% 1/10W R387 1-216-833-11 METAL CHIP 10K 5% 1/10W R388 1-216-837-11 METAL CHIP 22K 5% 1/10W The components identified by mark 0 or dotted line with mark 0 are critical for safety. Replace only with part number specified. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 67 Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks HCD-GN600 MAIN R390 1-216-833-11 METAL CHIP 10K 5% 1/10W R391 1-216-827-11 METAL CHIP 3.3K 5% 1/10W R392 1-216-825-11 METAL CHIP 2.2K 5% 1/10W R393 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R394 1-216-833-11 METAL CHIP 10K 5% 1/10W R395 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R396 1-216-833-11 METAL CHIP 10K 5% 1/10W R397 1-216-835-11 METAL CHIP 15K 5% 1/10W R398 1-216-861-11 METAL CHIP 2.2M 5% 1/10W R399 1-216-827-11 METAL CHIP 3.3K 5% 1/10W R401 1-216-833-11 METAL CHIP 10K 5% 1/10W R402 1-216-833-11 METAL CHIP 10K 5% 1/10W R419 1-216-809-11 METAL CHIP 100 5% 1/10W R420 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R421 1-216-833-11 METAL CHIP 10K 5% 1/10W R422 1-216-833-11 METAL CHIP 10K 5% 1/10W R427 1-216-809-11 METAL CHIP 100 5% 1/10W R429 1-216-809-11 METAL CHIP 100 5% 1/10W R430 1-216-809-11 METAL CHIP 100 5% 1/10W R431 1-216-845-11 METAL CHIP 100K 5% 1/10W R432 1-216-809-11 METAL CHIP 100 5% 1/10W R433 1-216-809-11 METAL CHIP 100 5% 1/10W R434 1-216-817-11 METAL CHIP 470 5% 1/10W R442 1-216-809-11 METAL CHIP 100 5% 1/10W R443 1-216-809-11 METAL CHIP 100 5% 1/10W R444 1-216-809-11 METAL CHIP 100 5% 1/10W R445 1-216-809-11 METAL CHIP 100 5% 1/10W R446 1-216-809-11 METAL CHIP 100 5% 1/10W R447 1-216-809-11 METAL CHIP 100 5% 1/10W R448 1-216-817-11 METAL CHIP 470 5% 1/10W R450 1-216-809-11 METAL CHIP 100 5% 1/10W R473 1-216-809-11 METAL CHIP 100 5% 1/10W R474 1-216-809-11 METAL CHIP 100 5% 1/10W R477 1-216-833-11 METAL CHIP 10K 5% 1/10W R478 1-216-833-11 METAL CHIP 10K 5% 1/10W R492 1-216-821-11 METAL CHIP 1K 5% 1/10W R493 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R501 1-216-821-11 METAL CHIP 1K 5% 1/10W R502 1-216-821-11 METAL CHIP 1K 5% 1/10W R503 1-216-809-11 METAL CHIP 100 5% 1/10W R504 1-216-809-11 METAL CHIP 100 5% 1/10W R505 1-216-817-11 METAL CHIP 470 5% 1/10W R506 1-216-817-11 METAL CHIP 470 5% 1/10W R507 1-216-817-11 METAL CHIP 470 5% 1/10W R509 1-216-833-11 METAL CHIP 10K 5% 1/10W R511 1-216-851-11 METAL CHIP 330K 5% 1/10W R513 1-216-864-11 METAL CHIP 0 5% 1/10W R517 1-216-833-11 METAL CHIP 10K 5% 1/10W R518 1-216-809-11 METAL CHIP 100 5% 1/10W R519 1-216-833-11 METAL CHIP 10K 5% 1/10W R521 1-216-809-11 METAL CHIP 100 5% 1/10W R522 1-216-809-11 METAL CHIP 100 5% 1/10W R523 1-216-833-11 METAL CHIP 10K 5% 1/10W R529 1-216-833-11 METAL CHIP 10K 5% 1/10W R530 1-216-833-11 METAL CHIP 10K 5% 1/10W R532 1-216-841-11 METAL CHIP 47K 5% 1/10W R535 1-216-817-11 METAL CHIP 470 5% 1/10W R536 1-216-809-11 METAL CHIP 100 5% 1/10W R537 1-216-817-11 METAL CHIP 470 5% 1/10W R538 1-216-809-11 METAL CHIP 100 5% 1/10W R539 1-216-809-11 METAL CHIP 100 5% 1/10W R540 1-216-809-11 METAL CHIP 100 5% 1/10W R541 1-216-809-11 METAL CHIP 100 5% 1/10W R542 1-216-833-11 METAL CHIP 10K 5% 1/10W R543 1-216-833-11 METAL CHIP 10K 5% 1/10W R544 1-216-833-11 METAL CHIP 10K 5% 1/10W R545 1-216-833-11 METAL CHIP 10K 5% 1/10W R549 1-216-833-11 METAL CHIP 10K 5% 1/10W R550 1-216-833-11 METAL CHIP 10K 5% 1/10W R560 1-216-809-11 METAL CHIP 100 5% 1/10W R561 1-216-809-11 METAL CHIP 100 5% 1/10W R563 1-216-833-11 METAL CHIP 10K 5% 1/10W R565 1-216-809-11 METAL CHIP 100 5% 1/10W R566 1-216-809-11 METAL CHIP 100 5% 1/10W R567 1-216-809-11 METAL CHIP 100 5% 1/10W R568 1-216-809-11 METAL CHIP 100 5% 1/10W R573 1-216-833-11 METAL CHIP 10K 5% 1/10W R574 1-216-833-11 METAL CHIP 10K 5% 1/10W R575 1-216-809-11 METAL CHIP 100 5% 1/10W R576 1-216-809-11 METAL CHIP 100 5% 1/10W R577 1-216-809-11 METAL CHIP 100 5% 1/10W R578 1-216-809-11 METAL CHIP 100 5% 1/10W R579 1-216-809-11 METAL CHIP 100 5% 1/10W R580 1-216-809-11 METAL CHIP 100 5% 1/10W R581 1-216-809-11 METAL CHIP 100 5% 1/10W R583 1-216-809-11 METAL CHIP 100 5% 1/10W R584 1-216-809-11 METAL CHIP 100 5% 1/10W R585 1-216-809-11 METAL CHIP 100 5% 1/10W R586 1-216-809-11 METAL CHIP 100 5% 1/10W R587 1-216-809-11 METAL CHIP 100 5% 1/10W R588 1-216-809-11 METAL CHIP 100 5% 1/10W R589 1-216-809-11 METAL CHIP 100 5% 1/10W R590 1-216-809-11 METAL CHIP 100 5% 1/10W R591 1-216-809-11 METAL CHIP 100 5% 1/10W R592 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R593 1-216-821-11 METAL CHIP 1K 5% 1/10W R594 1-216-821-11 METAL CHIP 1K 5% 1/10W R597 1-216-809-11 METAL CHIP 100 5% 1/10W R600 1-216-809-11 METAL CHIP 100 5% 1/10W R601 1-216-813-11 METAL CHIP 220 5% 1/10W R602 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R603 1-216-841-11 METAL CHIP 47K 5% 1/10W R604 1-216-841-11 METAL CHIP 47K 5% 1/10W R620 1-216-833-11 METAL CHIP 10K 5% 1/10W R621 1-216-821-11 METAL CHIP 1K 5% 1/10W R622 1-216-841-11 METAL CHIP 47K 5% 1/10W R623 1-216-833-11 METAL CHIP 10K 5% 1/10W R624 1-215-891-11 METAL OXIDE 680 5% 2W R625 1-216-821-11 METAL CHIP 1K 5% 1/10W R626 1-216-806-11 METAL CHIP 56 5% 1/10W R650 1-216-835-11 METAL CHIP 15K 5% 1/10W R651 1-216-853-11 METAL CHIP 470K 5% 1/10W R652 1-216-843-11 METAL CHIP 68K 5% 1/10W R653 1-216-821-11 METAL CHIP 1K 5% 1/10W R654 1-216-845-11 METAL CHIP 100K 5% 1/10W R655 1-216-845-11 METAL CHIP 100K 5% 1/10W R656 1-216-833-11 METAL CHIP 10K 5% 1/10W R670 1-216-833-11 METAL CHIP 10K 5% 1/10W R671 1-216-821-11 METAL CHIP 1K 5% 1/10W R672 1-216-841-11 METAL CHIP 47K 5% 1/10W www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 68 Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks HCD-GN600 R673 1-216-833-11 METAL CHIP 10K 5% 1/10W R674 1-215-891-11 METAL OXIDE 680 5% 2W R675 1-216-821-11 METAL CHIP 1K 5% 1/10W R676 1-216-806-11 METAL CHIP 56 5% 1/10W R851 1-216-825-11 METAL CHIP 2.2K 5% 1/10W R852 1-216-833-11 METAL CHIP 10K 5% 1/10W R853 1-216-422-11 METAL OXIDE 18 5% 1W R854 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R901 1-216-826-11 METAL CHIP 2.7K 5% 1/10W R902 1-216-825-11 METAL CHIP 2.2K 5% 1/10W R903 1-216-825-11 METAL CHIP 2.2K 5% 1/10W R904 1-216-832-11 METAL CHIP 8.2K 5% 1/10W R905 1-216-832-11 METAL CHIP 8.2K 5% 1/10W R906 1-216-821-11 METAL CHIP 1K 5% 1/10W R908 1-216-833-11 METAL CHIP 10K 5% 1/10W R913 1-216-841-11 METAL CHIP 47K 5% 1/10W < VARIABLE RESISTOR > RV301 1-238-019-11 RES, ADJ, CARBON 47K (REC LEVEL (L)) RV304 1-241-768-11 RES, ADJ, CARBON 220K (REC BIAS (L)) RV351 1-238-019-11 RES, ADJ, CARBON 47K (REC LEVEL (R)) RV354 1-241-768-11 RES, ADJ, CARBON 220K (REC BIAS (R)) < TRANSFORMER > T301 1-423-980-11 TRANSFORMER, BIAS OSCILLATION < VIBRATOR > X501 1-567-098-41 VIBRATOR, CRYSTAL (32.768kHz) X502 1-781-107-21 VIBRATOR, SERAMIC (16MHz) ************************************************************* 1-687-133-11 MOTOR (LD) BOARD ***************** ************************************************************* 1-687-134-11 MOTOR (TB) BOARD ***************** < CONNECTOR > CN742 1-784-727-11 CONNECTOR, FFC 5P ************************************************************* A-4731-347-A POWER AMP BOARD, COMPLETE **************************** 7-685-647-79 SCREW +BVTP 3X10 TYPE2 N-S < CAPASITOR > C501 1-126-963-11 ELECT 4.7uF 20% 50V C502 1-162-294-31 CERAMIC 0.001uF 10% 50V C503 1-162-282-31 CERAMIC 100PF 10% 50V C504 1-104-665-11 ELECT 100uF 20% 10V C507 1-136-495-11 FILM 0.068uF 5% 50V C508 1-136-495-11 FILM 0.068uF 5% 50V C509 1-128-560-11 ELECT 22uF 20% 100V C512 1-162-306-11 CERAMIC 0.01uF 20% 16V C513 1-164-159-11 CERAMIC 0.1uF 50V C516 1-104-665-11 ELECT 100uF 20% 10V C517 1-126-964-11 ELECT 10uF 20% 50V C523 1-162-306-11 CERAMIC 0.01uF 30% 16V C524 1-162-306-11 CERAMIC 0.01uF 30% 16V C526 1-126-964-11 ELECT 10uF 20% 50V C541 1-136-165-00 FILM 0.1uF 5% 50V C542 1-127-811-11 ELECT 3300uF 20% 50V C544 1-130-777-00 MYLAR 0.1uF 5% 100V C545 1-130-777-00 MYLAR 0.1uF 5% 100V C546 1-137-843-11 ELECT 2200uF 20% 100V C551 1-126-963-11 ELECT 4.7uF 20% 50V C552 1-162-294-31 CERAMIC 0.001uF 10% 50V C553 1-162-282-31 CERAMIC 100PF 10% 50V C554 1-104-665-11 ELECT 100uF 20% 10V C557 1-136-495-11 FILM 0.068uF 5% 50V C558 1-136-495-11 FILM 0.068uF 5% 50V C559 1-128-560-11 ELECT 22uF 20% 100V C581 1-126-965-91 ELECT 22uF 20% 50V C591 1-136-165-00 FILM 0.1uF 5% 50V C592 1-127-811-11 ELECT 3300uF 20% 50V C596 1-137-843-11 ELECT 2200uF 20% 100V < CONNECTOR > CN503 1-778-981-21 CONNECTOR, BOARD TO BOARD 13P CN504 1-770-722-11 CONNECTOR, BOARD TO BOARD 6P < DIODE > D501 8-719-991-33 DIODE 1SS133T-72 D502 8-719-991-33 DIODE 1SS133T-72 D503 8-719-947-70 DIODE MTZJ-T-72-18C D504 8-719-947-70 DIODE MTZJ-T-72-18C D506 8-719-991-33 DIODE 1SS133T-72 D507 8-719-991-33 DIODE 1SS133T-72 D508 8-719-991-33 DIODE 1SS133T-72 D509 8-719-991-33 DIODE 1SS133T-72 D511 8-719-991-33 DIODE 1SS133T-72 D541 8-719-510-68 DIODE D5SBA204101 D543 8-719-500-60 DIODE D5SBA20 D551 8-719-991-33 DIODE 1SS133T-72 D581 8-719-991-33 DIODE 1SS133T-72 < EARTH TERMINAL > * EP501 1-537-738-21 TERMINAL, EARTH * EP502 1-537-738-21 TERMINAL, EARTH < IC > IC501 6-600-169-01 IC STK412-240 < TRANSISTOR > Q501 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA Q503 8-729-140-82 TRANSISTOR 2SA988TP-PAFAEA Q504 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA Q505 8-729-119-79 TRANSISTOR 2SC2785TP-FEK Q506 8-729-119-79 TRANSISTOR 2SC2785TP-FEK Q510 8-729-119-79 TRANSISTOR 2SC2785TP-FEK Q511 8-729-119-79 TRANSISTOR 2SC2785TP-FEK Q514 8-729-119-79 TRANSISTOR 2SC2785TP-FEK Q516 8-729-119-79 TRANSISTOR 2SC2785TP-FEK Q517 8-729-119-76 TRANSISTOR 2SA1175TP-HFE Q518 8-729-119-79 TRANSISTOR 2SC2785TP-FEK Q551 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA Q581 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA MAIN MOTOR (LD) MOTOR (TB) POWER AMP www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 69 Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks HCD-GN600 The components identified by mark 0 or dotted line with mark 0 are critical for safety. Replace only with part number specified. < RESISTOR > R501 1-249-417-11 CARBON 1K 5% 1/4W F R502 1-249-437-11 CARBON 47K 5% 1/4W R503 1-249-411-11 CARBON 330 5% 1/4W R504 1-249-437-11 CARBON 47K 5% 1/4W R505 1-249-417-11 CARBON 1K 5% 1/4W F R506 1-249-434-11 CARBON 27K 5% 1/4W R507 1-249-441-11 CARBON 100K 5% 1/4W 0R508 1-234-499-21 ENCAPSULATED COMPONENT R509 1-260-076-11 CARBON 10 5% 1/2W 0R511 1-212-881-11 FUSIBLE 100 5% 1/4W 0R512 1-202-972-61 FUSIBLE 1 5% 1/4W R513 1-249-435-11 CARBON 33K 5% 1/4W R514 1-249-421-11 CARBON 2.2K 5% 1/4W F R515 1-249-433-11 CARBON 22K 5% 1/4W R516 1-249-429-11 CARBON 10K 5% 1/4W R517 1-249-429-11 CARBON 10K 5% 1/4W R518 1-249-435-11 CARBON 33K 5% 1/4W R519 1-249-439-11 CARBON 68K 5% 1/4W 0R520 1-215-869-11 METAL OXIDE 1K 5% 1W R521 1-249-441-11 CARBON 100K 5% 1/4W R522 1-249-441-11 CARBON 100K 5% 1/4W R523 1-249-440-11 CARBON 82K 5% 1/4W 0R524 1-215-869-11 METAL OXIDE 1K 5% 1W R527 1-249-438-11 CARBON 56K 5% 1/4W R528 1-249-437-11 CARBON 47K 5% 1/4W R529 1-249-433-11 CARBON 22K 5% 1/4W R530 1-249-433-11 CARBON 22K 5% 1/4W R531 1-247-891-00 CARBON 330K 5% 1/4W R532 1-249-441-11 CARBON 100K 5% 1/4W R533 1-249-437-11 CARBON 47K 5% 1/4W 0R539 1-215-889-00 METAL OXIDE 330 5% 2W R541 1-249-441-11 CARBON 100K 5% 1/4W R542 1-249-441-11 CARBON 100K 5% 1/4W R545 1-249-417-11 CARBON 1K 5% 1/4W F R546 1-249-433-11 CARBON 22K 5% 1/4W R547 1-249-437-11 CARBON 47K 5% 1/4W R548 1-249-437-11 CARBON 47K 5% 1/4W R551 1-249-417-11 CARBON 1K 5% 1/4W F R552 1-249-437-11 CARBON 47K 5% 1/4W R553 1-249-411-11 CARBON 330 5% 1/4W R554 1-249-437-11 CARBON 47K 5% 1/4W R555 1-249-417-11 CARBON 1K 5% 1/4W F R556 1-249-434-11 CARBON 27K 5% 1/4W R557 1-249-441-11 CARBON 100K 5% 1/4W 0R558 1-234-499-21 ENCAPSULATED COMPONENT R559 1-260-076-11 CARBON 10 5% 1/2W 0R561 1-212-881-11 FUSIBLE 100 5% 1/4W R564 1-249-433-11 CARBON 22K 5% 1/4W R565 1-249-433-11 CARBON 22K 5% 1/4W R568 1-249-429-11 CARBON 10K 5% 1/4W R569 1-249-437-11 CARBON 47K 5% 1/4W R570 1-249-429-11 CARBON 10K 5% 1/4W R572 1-249-441-11 CARBON 100K 5% 1/4W R577 1-247-807-31 CARBON 100 5% 1/4W R578 1-247-897-11 CARBON 560K 5% 1/4W R581 1-249-435-11 CARBON 33K 5% 1/4W R582 1-249-435-11 CARBON 33K 5% 1/4W R591 1-249-441-11 CARBON 100K 5% 1/4W R592 1-249-441-11 CARBON 100K 5% 1/4W < RELAY > RY501 1-515-920-11 RELAY < THERMISTOR > TH501 1-807-796-11 THERMISTOR TH502 1-807-796-11 THERMISTOR < TERMINAL > TM501 1-694-884-11 TERMINAL BOARD (4P) (SPEAKER) ************************************************************* 1-687-132-11 SENSOR BOARD ************** < CONNECTOR > CN731 1-785-329-21 PIN, CONNECTOR (LIGHT ANGLE)3P ************************************************************* A-4731-346-A SUB TRANS BOARD, COMPLETE *************************** < CAPACITOR > 0C971 1-113-925-11 CERAMIC 0.01uF 20% 250V C973 1-126-933-11 ELECT 100uF 20% 16V C975 1-126-768-11 ELECT 2200uF 20% 16V C976 1-164-159-11 CERAMIC 0.1uF 50V C977 1-164-159-11 CERAMIC 0.1uF 50V C978 1-164-159-11 CERAMIC 0.1uF 50V < CONNECTOR > CN971 1-568-106-11 PIN, CONNECTOR(3.96MM PITCH)4P CN974 1-564-321-00 PIN, CONNECTOR(3.96MM PITCH)2P CN976 1-506-469-11 PIN, CONNECTOR 4P < DIODE > D971 8-719-991-33 DIODE 1SS133T-72 D972 8-719-024-99 DIODE 11ES2-NTA2B D973 8-719-024-99 DIODE 11ES2-NTA2B D974 8-719-024-99 DIODE 11ES2-NTA2B D975 8-719-024-99 DIODE 11ES2-NTA2B < IC > IC971 6-703-546-01 IC TA7804LS < TRANSISTOR > Q971 8-729-119-79 TRANSISTOR 2SC2785TP-FEK < RESISTOR > R974 1-249-441-11 CARBON 100K 5% 1/4W R975 1-249-429-11 CARBON 10K 5% 1/4W < RELAY > 0RY971 1-755-276-11 RELAY, POWER POWER AMP SENSOR SUB TRANS www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 70 Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks HCD-GN600 < SWITCH > 0S901 1-786-055-21 SELECTOR, VOLTAGE < TRANSFORMER > 0T972 1-435-825-11 TRANSFORMER, POWER ************************************************************* 1-687-669-11 SW BOARD ********* < SWITCH > S751 1-786-514-11 SWITCH, LEVER (SLIDE) (LEVER) ************************************************************* 1-686-930-11 TRANS BOARD ************ < CAPACITOR > C941 1-128-576-11 ELECT 100uF 20% 63V < CONNECTOR > CN997 1-564-509-11 PLUG, CONNECTOR 6P * CN998 1-564-510-11 PLUG, CONNECTOR 7P < DIODE > D977 8-719-024-99 DIODE 11ES2-NTA2B < FUSE HOLDER > FH9741 1-533-233-11 FUSE HOLDER FH9742 1-533-233-11 FUSE HOLDER FH9751 1-533-233-11 FUSE HOLDER FH9752 1-533-233-11 FUSE HOLDER FH9761 1-533-233-11 FUSE HOLDER FH9762 1-533-233-11 FUSE HOLDER FH9771 1-533-233-11 FUSE HOLDER FH9772 1-533-233-11 FUSE HOLDER FH9781 1-533-233-11 FUSE HOLDER FH9782 1-533-233-11 FUSE HOLDER < RESISTOR > 0R941 1-217-637-00 FUSIBLE 1 5% 1/4W 0R952 1-219-120-11 FUSIBLE 0.15 5% 1/4W ************************************************************* A-4731-329-A VOLUME BOARD, COMPLETE ************************ < CAPACITOR > C614 1-162-294-31 CERAMIC 0.001uF 10% 50V C615 1-124-589-11 ELECT 47uF 20% 16V C750 1-164-159-11 CERAMIC 0.1uF 50V C751 1-164-159-11 CERAMIC 0.1uF 50V C752 1-164-159-11 CERAMIC 0.1uF 50V < CONNECTOR > CN605 1-568-860-11 SOCKET, CONNECTOR 17P < DIODE > D1001 6-500-529-01 DIODE SLI-325URT31W (VOL 1) D1002 6-500-529-01 DIODE SLI-325URT31W (VOL 2) D1003 6-500-529-01 DIODE SLI-325URT31W (VOL 3) D1004 6-500-529-01 DIODE SLI-325URT31W (VOL 4) D1005 6-500-529-01 DIODE SLI-325URT31W (VOL 5) D1006 6-500-529-01 DIODE SLI-325URT31W (VOL 6) D1007 6-500-529-01 DIODE SLI-325URT31W (VOL 7) D1008 6-500-529-01 DIODE SLI-325URT31W (VOL 8) D1009 6-500-529-01 DIODE SLI-325URT31W (VOL 9) D1010 6-500-529-01 DIODE SLI-325URT31W (VOL 10) D1011 6-500-529-01 DIODE SLI-325URT31W (VOL 11) < IC > IC603 6-600-174-01 IC RPM7240-H4 < TRANSISTOR > Q1001 8-729-116-02 TRANSISTOR BA1A4M-TP Q1002 8-729-116-02 TRANSISTOR BA1A4M-TP Q1003 8-729-116-02 TRANSISTOR BA1A4M-TP Q1004 8-729-116-02 TRANSISTOR BA1A4M-TP Q1005 8-729-116-02 TRANSISTOR BA1A4M-TP Q1006 8-729-116-02 TRANSISTOR BA1A4M-TP < RESISTOR > R625 1-249-401-11 CARBON 47 5% 1/4W F R750 1-249-410-11 CARBON 270 5% 1/4W F R759 1-249-427-11 CARBON 6.8K 5% 1/4W F R760 1-249-429-11 CARBON 10K 5% 1/4W R761 1-249-431-11 CARBON 15K 5% 1/4W R762 1-249-433-11 CARBON 22K 5% 1/4W R763 1-249-435-11 CARBON 33K 5% 1/4W R765 1-249-413-11 CARBON 470 5% 1/4W F R766 1-249-415-11 CARBON 680 5% 1/4W F R767 1-249-417-11 CARBON 1K 5% 1/4W F R768 1-249-419-11 CARBON 1.5K 5% 1/4W F R769 1-249-419-11 CARBON 1.5K 5% 1/4W F R770 1-249-421-11 CARBON 2.2K 5% 1/4W F R771 1-247-843-11 CARBON 3.3K 5% 1/4W R772 1-249-425-11 CARBON 4.7K 5% 1/4W F R773 1-249-427-11 CARBON 6.8K 5% 1/4W F R774 1-249-429-11 CARBON 10K 5% 1/4W R775 1-249-431-11 CARBON 15K 5% 1/4W R776 1-249-433-11 CARBON 22K 5% 1/4W R777 1-249-435-11 CARBON 33K 5% 1/4W R1001 1-249-413-11 CARBON 470 5% 1/4W F R1002 1-249-413-11 CARBON 470 5% 1/4W F R1003 1-249-413-11 CARBON 470 5% 1/4W F R1004 1-249-413-11 CARBON 470 5% 1/4W F R1005 1-249-413-11 CARBON 470 5% 1/4W F R1006 1-249-413-11 CARBON 470 5% 1/4W F R1007 1-249-413-11 CARBON 470 5% 1/4W F R1008 1-249-413-11 CARBON 470 5% 1/4W F R1009 1-249-413-11 CARBON 470 5% 1/4W F R1010 1-249-413-11 CARBON 470 5% 1/4W F R1011 1-249-413-11 CARBON 470 5% 1/4W F SUB TRANS The components identified by mark 0 or dotted line with mark 0 are critical for safety. Replace only with part number specified. VOLUME SW TRANS www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 71 Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks HCD-GN600 The components identified by mark 0 or dotted line with mark 0 are critical for safety. Replace only with part number specified. < SWITCH > S748 1-476-504-11 ENCODER, ROTARY (VOLUME) S750 1-762-875-21 SWITCH, KEYBOARD (DISPLAY) S759 1-762-875-21 SWITCH, KEYBOARD (SURROUND SPEAKER MODE) S760 1-762-875-21 SWITCH, KEYBOARD (P.FILE) S761 1-762-875-21 SWITCH, KEYBOARD (ILLUMINATION) S762 1-762-875-21 SWITCH, KEYBOARD (GAME EQ) S763 1-762-875-21 SWITCH, KEYBOARD (GROOVE) S765 1-762-875-21 SWITCH, KEYBOARD (EDIT/DIRECTION) S766 1-762-875-21 SWITCH, KEYBOARD (FM MODE/REPEAT) S767 1-762-875-21 SWITCH, KEYBOARD (TUNER MEMORY/PLAY MODE) S768 1-762-875-21 SWITCH, KEYBOARD (AMP MENU) S769 1-762-875-21 SWITCH, KEYBOARD (MUSIC EQ) S770 1-762-875-21 SWITCH, KEYBOARD (MOVIE EQ) S771 1-762-875-21 SWITCH, KEYBOARD (EFFECT ON/OFF) S773 1-786-528-11 SWITCH, ROTARY (<,,,M,m,PUSH ENTER) ************************************************************ MISCELLANEOUS *************** 5 1-920-838-32 WIRE (FLAT TYPE) (11 CORE) 6 1-693-603-11 TUNER (FM/AM) 70 1-773-040-11 WIRE (FLAT TYPE) (17 CORE) 73 1-773-110-11 WIRE (FLAT TYPE) (19 CORE) 75 1-796-487-31 DECK, MECHANICAL 79 1-751-688-11 WIRE (FLAT TYPE) (13 CORE) 0103 1-777-071-53 CORD, POWER (E51) 0103 1-783-941-12 CORD, POWER (AR) 0103 1-791-901-12 CORD, POWER (E2,MX) 152 1-776-182-11 WIRE (FLAT TYPE) (5 CORE) 226 1-782-817-11 WIRE (FLAT TYPE) (16 CORE) 227 1-775-280-11 WIRE (FLAT TYPE) (31 CORE) 0229 A-4735-357-A BASE ASSY, OP (including KSS-213DCP) 230 1-471-035-11 MAGNET ASSY 0F974 1-533-473-11 FUSE, GLASS TUBE (DIA. 5) (T6.3AL 250V) 0F975 1-533-473-11 FUSE, GLASS TUBE (DIA. 5) (T6.3AL 250V) 0F976 1-533-473-11 FUSE, GLASS TUBE (DIA. 5) (T6.3AL 250V) 0F977 1-533-473-11 FUSE, GLASS TUBE (DIA. 5) (T6.3AL 250V) 0F978 1-533-471-11 FUSE, GLASS TUBE (DIA. 5) (T4AL 250V) M741 A-4723-963-A MOTOR ASSY, TABLE M751 A-4737-553-A MOTOR ASSY, LOADING M891 1-763-072-11 FAN, DC RE701 1-477-680-11 ENCODER, ROTARY 0T910 1-439-556-11 POWER TRANSFORMER VOLUME www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com HCD-GN600 REVISION HISTORY Clicking the version allows you to jump to the revised page. Also, clicking the version at the upper right on the revised page allows you to jump to the next revised page. Ver. Date Description of Revision 1.0 2003.04 New www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com
