SERVICE MANUAL COMPACT DISC DECK RECEIVER AEP Model SPECIFICATIONS HCD-E301 Ver 1.0 2001.05 HCD-E301 is the amplifier, CD player, tape deck and tuner section in CMT-E301. 9-873-906-11 Sony Corporation 2001E0500-1 Home Audio Company C 2001.5 Shinagawa Tec Service Manual Production Group Amplifier section DIN power output (rated) 4.5 + 4.5 W (4 Ω at 1 kHz, DIN) Continuous RMS power output (reference) 5 + 5 W (4 Ω at 1 kHz, 10% THD) Music power output (reference) 13 + 13 W CD player section System Compact disc and digital audio system Laser Semiconductor laser (λ=780 nm) Emission duration: continuous Frequency response 20 Hz - 20 kHz (±0.5 dB) Tape player section Recording system 4-track 2-channel stereo Frequency response 50 - 13 000 Hz (±3 dB), using Sony TYPE I cassette Tuner section FM stereo, FM/AM superheterodyne tuner FM tuner section Tuning range 87.5 - 108.0 MHz Antenna FM lead antenna Intermediate frequency 10.7 MHz AM tuner section Tuning range 531 -1 602 kHz (with the interval set at 9 kHz) Antenna Built-in ferrite bar antenna Intermediate frequency 450 kHz General Power requirements 230 V AC, 50/60 Hz Power consumption 30 W 0.9 W (in the standby mode) Dimensions (w/h/d): Approx. 145 × 238 × 238 mm Mass: Approx. 2.8 kg Design and specifications are subject to change without notice. CD Model Name Using Similar Mechanism HCD-EP30 Section CD Mechanism Type CS-21SC-1280 TAPE Model Name Using Similar Mechanism HCD-EP30 Section Tape Transport Mechanism Type TCM125-2 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 2 HCD-E301 Notes on chip component replacement • Never reuse a disconnected chip component. • Notice that the minus side of a tantalum capacitor may be dam- aged by heat. Flexible Circuit Board Repairing • Keep the temperature of the soldering iron around 270 ˚C dur- ing repairing. • Do not touch the soldering iron on the same conductor of the circuit board (within 3 times). • Be careful not to apply force on the conductor when soldering or unsoldering. CAUTION Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous ra- diation exposure. SAFETY-RELATED COMPONENT WARNING!! COMPONENTS IDENTIFIED BY MARK 0 OR DOTTED LINE WITH MARK 0 ON THE SCHEMATIC DIAGRAMS AND IN THE PARTS LIST ARE CRITICAL TO SAFE OPERATION. REPLACE THESE COMPONENTS WITH SONY PARTS WHOSE PART NUMBERS APPEAR AS SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUB- LISHED BY SONY. The following caution label is located inside the unit. This appliance is classified as a CLASS 1 LASER product. The CLASS 1 LASER PRODUCT MARKING is located on the rear exterior. TABLE OF CONTENTS 1. SERVICING NOTES ................................................ 3 2. GENERAL ................................................................... 4 3. DISASSEMBLY 3-1. Disassembly Flow ........................................................... 6 3-2. Front Panel Section ......................................................... 7 3-3. MAIN Board ................................................................... 7 3-4. CD Cabinet Section......................................................... 8 3-5. CD Mechanism Deck (CS-21SC-1280) ......................... 8 3-6. Tape Mechanism Deck (TCM125-2) .............................. 9 3-7. Cassette Lid ..................................................................... 9 4. MECHANICAL ADJUSTMENTS ....................... 10 5. ELECTRICAL ADJUSTMENTS ......................... 10 6. DIAGRAMS 6-1. Note for Printed Wiring Boards and Schematic Diagrams ....................................................... 13 6-2. Schematic Diagram – MAIN Board (1/2) – .................. 14 6-3. Schematic Diagram – MAIN (2/2)/HEADPHONE Boards – ......................... 15 6-4. Printed Wiring Boards – MAIN/HEADPHONE Boards – .................................. 16 6-5. Printed Wiring Board – CASSETTE Board – ............... 17 6-6. Schematic Diagram – CASSETTE Board – .................. 17 6-7. Printed Wiring Board – DISPLAY Board – .................. 18 6-8. Schematic Diagram – DISPLAY Board – ..................... 19 6-9. Schematic Diagram – POWER Board – ........................ 20 6-10. Printed Wiring Board – POWER Board – ..................... 21 6-11. IC Pin Function Description ........................................... 23 7. EXPLODED VIEWS 7-1. Cabinet Section ............................................................... 24 7-2. Front Panel Section-1...................................................... 25 7-3. Front Panel Section-2...................................................... 26 7-4. CD Cabinet Section......................................................... 27 8. ELECTRICAL PARTS LIST ............................... 28 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 3 HCD-E301 NOTES ON HANDLING THE OPTICAL PICK-UP BLOCK OR BASE UNIT The laser diode in the optical pick-up block may suffer electro- static break-down because of the potential difference generated by the charged electrostatic load, etc. on clothing and the human body. During repair, pay attention to electrostatic break-down and also use the procedure in the printed matter which is included in the repair parts. The flexible board is easily damaged and should be handled with care. NOTES ON LASER DIODE EMISSION CHECK The laser beam on this model is concentrated so as to be focused on the disc reflective surface by the objective lens in the optical pick-up block. Therefore, when checking the laser diode emis- sion, observe from more than 30 cm away from the objective lens. LASER DIODE AND FOCUS SEARCH OPERATION CHECK 1. Press the I/1 button to the power ON with no disc inserted and press the [CD] button. 2. Open the lid for CD. 3. Turn on SW600 as following figure. 4. Confirm the laser diode emission while observing the object- ing lens. When there is no emission, Auto Power Control cir- cuit or Optical Pick-up is broken. Objective lens moves up and down five times for the focus search. SECTION 1 SERVICING NOTES TO PREVENT ‘TAPE OSCILLATION SOUND AT VOLUME’ MAXIMUM SETTING (W/O TAPE) Headphone wire dressing: a.) Draw the wire from Main board to Headphone Jack board along the bottom side of heatsink. b.) The wire must be kept away from the top side of Cassette board at least 30 mm. SW600 CASSETTE board MAIN board HEADPHONE board at least 30 mm heatsink www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 4 HCD-E301 SECTION 2 GENERAL This section is extracted from instruction manual. LOCATION OF CONTROLS – Front Panel – Cassette compartment qd (12) CD 4 (8, 9, 13, 15) Display Window 5 (9, 18) ENTER/PGM w; (7, 8, 9, 10, 12, 15) ISS 0 (13) MEGA BASS 8 (14) MONO STEREO 0 (11) MUSIC MENU 9 (14) PHONES jack ws PRESET +/– qs (10, 11) REMAIN 4 (9) Remote sensor wk REPEAT wj (8) SHUFFLE wa (8) TAPE 3 (12) TIMER indicator 2 (15) TUNER 6 (10, 13, 15) TUNER MEM w; (10) TUNING + wd (10, 11) TUNING – wf (10, 11) VOLUME control qa (15) 1 2 3 4 5 6 7 q; 9 8 qa qs w; wa ws wd wf wg wh wj wk qd qf qj qh ql qk qg BUTTON DESCRIPTIONS @/1 (power) 1 (6, 10) CD . m (go back) wf (8, 9) M > (go forward) wd (8, 9) u (play/pause) wg (8, 9) Z PUSH OPEN/CLOSE 7 (8) x (stop) wh (8, 9) TAPE M (fast forward) qh (12) X (pause) qf (12, 13) N (play) qk (12, 15) z (recording) ql (13) m (rewind) qj (12) xZ (stop/eject) qg (12, 13) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 5 HCD-E301 CD/REMAIN 3 (8, 9, 13, 15) CLOCK/TIMER/SLEEP SET qf (7, 15) MEGA BASS 2 (14) MUSIC MENU w; (14) PRESET +/– qj (10, 11) REPEAT qs (8) SHUFFLE 7 (8) TAPE ql (12) TIMER ON/OFF qd (15) TUNER/BAND 5 (10, 13, 15) TUNER MEM/ENTER/PGM 6 (7, 8, 9, 10, 11, 15) TUNING/CLOCK/TIMER +/– qk (7, 10, 11, 15) VOLUME +/– 4 (15) BUTTON DESCRIPTIONS M (fast forward) > (go forward) 0 (8, 9) . (go back) m (rewind) qa (8, 9) u (play/pause) 8 (8, 9) `/1 (power) 1 (6, 10) x (stop) 9 (8, 9) Remote Control 1 2 34 5 6 7 8 9 q; qa qs qf qd qg qh qj qk ql w; Setting the time 1 Turn on the system. 2 Press CLOCK/TIMER/SLEEP SET on the remote. The clock indication appears. 3 Press TUNING/CLOCK/TIMER + or � on the remote repeatedly to set the time. 4 Press ENTER/PGM (TUNER MEM/ ENTER/PGM on the remote). The clock starts working. Tip If you made a mistake, perform from step 2. To change the preset time Perform from step 2. Note The clock settings are canceled when you disconnect the power cord or if a power failure occurs. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com HCD-E301 6 • This set can be disassembled in the order shown below. 3-1. DISASSEMBLY FLOW SECTION 3 DISASSEMBLY 3-4. CD CABINET SECTION (Page 8) 3-2. FRONT PANEL SECTION (Page 7) 3-6. TAPE MECHANISM DECK (TCM125-2) (Page 9) 3-5. CD MECHANISM DECK (CS-21SC-1280) (Page 8) 3-7. CASSETTE LID (Page 9) 3-3. MAIN BOARD (Page 7) SET www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com HCD-E301 7 3-3. MAIN BOARD Note: Follow the disassembly procedure in the numerical order given. 3-2. FRONT PANEL SECTION 8 connector (CN203) 5 two screws (+K3 × 5) 3 two screws (BTP2.6 × 10) 1 screw (BVTP3 × 10) 4 two screws (BVTP3 × 10) 5 two screws (+K3 × 5) 5 two screws (+K3 × 5) 9 connector (CN402) 0 connector (SW600) qa front panel section 7 2 antenna cover cabinet 6 claw 6 connector (CN202) 5 connector (CN201) 4 connector (CN302) 3 connector (CN301) 2 connector (CN101) 1 connector (CN204) 9 MAIN board 7 screw (+BTP2.6 × 8) 8 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com HCD-E301 8 3-4. CD CABINET SECTION 3-5. CD MECHANISM DECK (CS-21SC-1280) 1 two screws (BTP2.6 × 8) 2 CD cabinet section 1 two screws (BVTP3 × 10) 2 plastic cover 7 vibration proof rubber (pink) 7 vibration proof rubber (pink) 4 four fiber washers 3 four pulley screws 7 vibration proof rubber (brown) 7 vibration proof rubber (brown) 8 CD mechanism deck (CS-21SC-1280) 5 6 two spring clamps 6 two spring clamps www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com HCD-E301 9 3-6. TAPE MECHANISM DECK (TCM125-2) 3-7. CASSETTE LID 4 cassette board 3 1 connector (CN701) 2 two screws (BTP2.6 × 6) 6 two screws (BVTP3 × 10) 6 two screws (BVTP3 × 10) 7 tape mechanism deck (TCM125-2) 5 Open the cassette lid. 1 Open the cassette lid. 3 cassette lid 2 claw 2 claw www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 10 HCD-E301 SECTION 4 MECHANICAL ADJUSTMENTS SECTION 5 ELECTRICAL ADJUSTMENTS Tape Speed Adjustment Setting: Function: TAPE Procedure: 1. Playback WS-48A (tape center) in the FWD state. 2. Adjsut the volume in CAPSTAN/REEL motor (M201) so that the frequency counter reading becomes 3,000 Hz. Specified Value: 2,985 to 3,015 Hz 3. Confirm that the frequency at the beginning and that at the end of tape winding are between 2,955 to 3,045 Hz. Adjustment Location: PRECAUTION 1. Setting MEGA BASS switch : OFF TAPE DECK SECTION 0 dB=0.775 V Test tape Type Signal Used for WS-48A 3 kHz, 0 dB Tape Speed Adjustment P-4-A063 6.3 kHz, –10 dB Head Azimuth Adjustment frequency counter test tape WS-48A (3 kHz, 0 dB) set HEADPHONE board PHONES jack (JK401) – + 32 Ω CAPSTAN/REEL motor (M201) Tape Speed Adjustment Mode Tension Meter Meter Reading FWD CQ-403A more than 100 g (more than 3.53 oz) • Tape Tension Measurement PRECAUTION 1. Clean the following parts with a denatured-alcohol-moistened swab : record/playback head pinch roller erase head rubber belts capstan idlers 2. Demagnetize the record/playback head with a head demagne- tizer. (Do not bring the head magnetizer close to the erase head.) 3. Do not use a magnetized screwdriver for the adjustments. 4. After the adjustments, apply suitable locking compound to the parts adjusted. 5. The adjustments should be performed with the rated power supply voltage unless otherwise noted. • Torque Measurement Mode Torque Meter Meter Reading 2.95 – 6.86 mN•m FWD CQ-102C (30 – 70 g•cm) (0.42 – 0.97 oz•inch) 0.15 – 5.39 mN•m FWD CQ-102C (1.5 – 5.5 g•cm) Back Tension (0.021 – 0.076 oz•inch) more than 5.89 mN•m FF CQ-201B (more than 60 g•cm) (more than 0.83 oz•inch) more than 5.89 mN•m REW CQ-201B (more than 60 g•cm) (more than 0.83 oz•inch) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 11 HCD-E301 2. Turn the adjustment screw and check output peaks. If the peaks do not match for L-CH and R-CH, turn the adjustment screw so that outputs match within 1dB of peak. 3. Mode: Playback (FWD) 4. Repeat step 1 to 3 in playback (REV) mode. 5. After the adjustments, apply suitable locking compound to the parts adjusted. Screw position L-CH peak within 1dB Output level L-CH peak R-CH peak within 1dB Screw position R-CH peak test tape P-4-A063 (6.3 kHz, –10 dB) L-CH R-CH HEADPHONE board PHONES jack (JK401) oscilloscope V H + + – – screen pattern in phase good wrong 45 ° 90 ° 135 ° 180 ° 32 Ω 32 Ω set Record/Playback Head Azimuth Adjustment Procedure: 1. Mode: Playback (FWD) level meter test tape P-4-A063 (6.3 kHz, –10 dB) set HEADPHONE board PHONES jack (JK401) 32 Ω + – Adjustment Location: Record/Playback/Erase Head. Note: Refer to “3-7. CASSETTE LID” (see page 9) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 12 HCD-E301 Adjustment Location and Connecting Points – MAIN BOARD (Component Side) – L104 FM Frequency Coverage Adjustment T102 AM Frequency Coverage Adjustment TC102 } AM Tracking L110 Adjustment L103 FM Tracking TC101 } Adjustment – MAIN BOARD (Conductor Side) – TP10 (FM VT) TP11 (AM VT) IC101 AM FREQUENCY COVERAGE ADJUSTMENT Adjustment Part Frequency Display Reading on Digital Voltmeter Confirmation 531 kHz 1.5 ± 0.2 V T102 1,602 kHz 7.3 ± 0.3 V AM TRACKING ADJUSTMENT Adjust for a maximum reading on level meter L110 603 kHz TC102 1,404 kHz FM FREQUENCY COVERAGE ADJUSTMENT Adjustment Part Frequency Display Reading on Digital Voltmeter L104 87.6 MHz 2.1 ± 0.2 V Confirmation 108 MHz 7.0 ± 0.4 V FM TRACKING ADJUSTMENT Adjust for a maximum reading on level meter L103 89.9 MHz TC101 105.9 MHz TUNER SECTION 0 dB=1 µV [AM] Setting: Function : TUNER Band switch: AM [FM] Setting: Function : TUNER Band switch: FM • Repeat the procedures in each adjustment several times, and the frequency coverage and tracking adjustments should be finally done by the trimmer capacitors. AM RF signal generator 30% amplitude modulation by 400 Hz signal Output level: as low as possible Put the lead-wire antenna close to the set. + – level meter set 32 Ω HEADPHONE board PHONES jack (JK401) FM RF signal generator 22.5 kHz frequency deviation by 400 Hz signal Output level: as low as possible + – level meter set 32 Ω 0.01 µF MAIN board FM ANT HEADPHONE board PHONES jack (JK401) digital voltmeter 100 kΩ MAIN board TP10 (FM VT) TP11 (AM VT) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com HCD-E301 13 13 SECTION 6 DIAGRAMS Note on Schematic Diagram: • All capacitors are in µF unless otherwise noted. pF: µµF 50 WV or less are not indicated except for electrolytics and tantalums. • All resistors are in Ω and 1/4 W or less unless otherwise specified. • 2 : nonflammable resistor. • C : panel designation. Note on Printed Wiring Board: • W : indicates side identified with part number. • : Pattern from the side which enables seeing. (The other layers' patterns are not indicated.) • A : B+ Line. • H : adjustment for repair. • Voltages are taken with a VOM (Input impedance 10 MΩ). Voltage variations may be noted due to normal produc- tion tolerances. • Waveforms are taken with a oscilloscope. Voltage variations may be noted due to normal produc- tion tolerances. • Circled numbers refer to waveforms. • Signal path. F : FM f : AM E : TAPE PLAY a : RECORD J : CD PLAY 6-1. NOTE FOR PRINTED WIRING BOARDS AND SCHEMATIC DIAGRAMS • Circuit Boards Location MAIN board HEADPHONE board CASSETTE board DISPLAY board POWER board Note: The components identified by mark 0 or dotted line with mark 0 are critical for safety. Replace only with part number specified. w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com HCD-E301 14 14 IC B/D IC B/D MAIN BOARD (2/2) 1 DSIPLAY BOARD A 1 4.5 (4.3) L110, TC102 AM TRACKING T102 AM FREQUENCY COVERAGE L103, TC101 FM TRACKING L104 FM FREQUENCY COVERAGE 0 (0.7) 5.4 (0.1) 0 1 (0) 5.2 (0) 5.2 (6.2) 5.2 (6.2) 0 (6.2) 1.3 1.3 1.2 (0.4) 4.5 (0.1) 4.5 (4.3) 4.5 (5.6) 4.5 (4.3) 0 4.5 (0.1) 0 (0.7) 0.2 (0.4) 5.2 (5.4) 1.3 1.3 5.2 (6.2) 5.2 (6.2) 2.8 (3.6) 0 5.2 (6.2) 5.2 (6.2) 1.3 1.3 0.3 (0.5) 0 0 (2.6) 2.6 (0) 5.1 0.9 0.9 2.4 (1.5) 2.6 2.5 0.1 0.1 5.4 0 0.1 (3.1) 0 9.3 9.2 8.5 0.7 0 0 FM LEAD ANTENNA ANT1 FM ANT 75Ω COAXIAL C157 0.1 C104 0.001 L103 FM RF C105 0.001 L104 FM OSC C111 0.001 TP10 (FM VT) R112 3.3k + 10V 0.001 0.01 1.2k 0.001 + 50V 0.015 0.015 3.9k + + 3.9k 50V 50V 6.8k 6.8k 0.0033 0.0033 + + + 50V 3.3k 50V 50V Q103 STEREO/MONO SWITCHING Q102 FM/AM BAND SELECT SWITCH Q101 FM OSC BUFFER IC101 FM/AM IF AMB MIX, MPX, DET, OSC IC102 FM/AM PLL 4.7k 100p 0.001 0.022 5.6k 0.01 2.2k 50V 5.6k + + 0.1 0.1 7.2MHz + MTZJ-5.1 + 10V 1µH Q116, 209, 210 TUNER B+ SWITCH 0.1 CN101 8P 0.047 AM FERRITE-ROD ANTENNA 1µH AM OSC 0.047 + 50V TP11 (AM VT) 0.022 0.022 10.7MHz 450kHz + 50V BUFFER + 0.047 MAIN BOARD (1/2) 1N4148TP 1N4148TP U 1 u U 2 u U 3 u U 4 u 2SC1923 2.2P 10.7MHz 16V RDSCL RDSDA PLLCE PLLDI PLLCL STOUT SIG ST 470 16V 18P 4.7k 6-2. SCHEMATIC DIAGRAM – MAIN Board (1/2) – • See page 21 for Waveform. • See page 22 for IC Block Diagrams. • Voltages and waveforms are dc with respect to ground under no-signal (detuned) conditions. no mark : FM ( ) : AM (Page 19) (Page 15) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com HCD-E301 15 15 IC B/D POWER BOARD CN402 E CASSETE BOARD B MAIN BOARD (1/2) 1 DISPLAY BOARD D DISPLAY BOARD C 9P 9P 5.3 4.8 7.8 0 0 3.6 3.9 3.9 3.9 3.9 3.9 3.9 3.9 3.9 3.9 3.9 3.9 3.9 3.9 3.9 3.9 3.9 3.6 0 0 3.9 0.1 1.9 1.4 2.1 1.9 2.1 1.4 5.6 6.2 13.5 9.9 9.3 13.7 0 MEGA BASS ON : 0.1 OFF : 0.7 0 MEGA BASS ON : 0.1 OFF : 0.7 0.8 (9.5) 13.7 0.8 (10) 0.6 (13.6) 13.7 13.6 (12.9) 13.6 (0) 0 (0.7) 0.6 (0) 13.7 13.7 13 0.3 0.7 0 0 [0.6] 0 0 [0.6] 0 [0.6] 0 [1.1] 0 16.4 0.6 0.6 0 16.1 8.7 8.7 16.1 16.7 8.7 CN201 9P 3.9k 3.9k 50V + + 1 50V Q201, 202 REC AMP + + + 4700p + 0.1 0.1 0.1 0.0082 0.0039 0.0033 0.047 8.2k 0.027 0.1 0.1 0.1 0.0082 0.0039 5.6k 8.2k 0.027 0.047 0.0033 + 4.7 50V + 50V 6.8k 0.001 8.2k 4.7 50V + + 50V + + 50V 50V 4.7 50V 6.8k 8.2k 0.001 4.7k 4.7k 2.2k 3.3k 2.2k 3.3k 50V + IC203 FUNCTION SELECT SWITCH, ELECTRICAL VOLUME MTZJ-6.2B Q312 +6V REGULATOR + 0.022 50V + + 10V MTZN-10B Q313 +9V REGULATOR + 0.022 + MTZN-10B 4.7k Q310, 311 REGULATOR CONTROL SWITCH Q305, 306 B+ SWITCH 0.022 + 50V + DC_15V 0.1 + + 50V Q301, 302 MUTING Q308, 309 +9V REGULATOR 0.001 + 16V + 16V + 50V 0.001 50V + Q314 MUTING CONTROL SWITCH IC301 POWER AMP + 25V + + 0.15 0.15 + + 25V PHONES CN301 5P + – + – R L SPEAKER IMPEDANCE USE 4Ω + – + – BIAS CIRCUIT, HEAT OPERATION PROTECTION CIRCUIT MAIN BOARD (2/2) CN202 4P M201 (CAPSTAN/REEL) S201 (PLAY) 0.1 + Q205, 206 MEGA BASS ON DRIVE 1N4148TP 1N4148TP 1N4148TP 1N4148TP 1N4148TP 1N4148TP 1N4148TP U 1 u U 2 u U 3 u U 4 u BEAT RL RR GND PL PR 9V SYNC COTR 0.047 2200p 16V 16V 16V 5.6k 2SD1616-L + 2SD1616-L 2SD1616-L 1N4148TP 1N4148TP 1N4148TP 1N4148TP 2.7k 2.7k 2200p 9P *CD BLOCK *SUPPLIED AS THE ASSEMBLED BLOCK CDDATA CDCLK CDRS DAT CLK CE DBBS BEAT SYNC 9K/10K MUTE PSW GND LED V+ TU –SW TA –SW CD –SW 6V 6 1 1 2 3 4 5 6 7 5 1 HEADPHONE BOARD 3.3k 3.3k SPK301 6-3. SCHEMATIC DIAGRAM – MAIN (2/2)/HEADPHONE Boards – • See page 22 for IC Block Diagram. • Voltages are dc with respect to ground under no-signal (detuned) conditions. no mark : TUNER (FM/AM) ( ) : CD PLAY [ ] : TAPE PLAY (Page 17) (Page 14) (Page 19) (Page 19) (Page 20) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com HCD-E301 16 16 MAIN BOARD L110 AM FERRITE-ROD ANTENNA A K A K A T102 AM OSC L103 FM RF + 1 2 3 B C E E C B E C B + + + + + + + + + A K + + K A TP10 (FM VT) TP11 (AM VT) B C E E C B E C B E C B + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + FM LEAD ANTENNA FM ANT 75Ω COAXIAL ANT101 E C B E C B E C B E C B B C E E C B E C B B C E B C E B C E E C B E C B B C E E C B B C E *CD BLOCK * SUPPLIED AS THE ASSEMBLED BLOCK SPEAKER (IMPEDANCE USE 4Ω) SPK301 + – + – L R A K K A K K K A A K A A K K K K K K A A A A K A A A A K IC101 IC102 IC203 IC301 A K A K U04 FM OSC 1 6 E POWER BOARD CN402 S201 (PLAY) M201 (CAPSTAN/REEL) M 2 1 3 4 C B DISPLAY BOARD CASSETTE BOARD A DISPLAY BOARD D DISPLAY BOARD R413 HEADPHONE BOARD R412 JK401 PHONES 3 4 5 6 1 2 7 1 5 A B C D E F G H I 1 2 3 4 5 6 7 8 9 10 6-4. PRINTED WIRING BOARDS – MAIN/HEADPHONE Boards – • See page 13 for Circuit Boards Location. • Semiconductor Location Ref. No. Location D101 B-4 D102 B-5 D103 B-8 D104 C-9 D105 B-5 D302 G-6 D303 G-6 D306 F-6 D307 H-8 D308 G-7 D310 H-8 D311 H-8 D312 F-6 D314 F-7 D316 F-6 D317 H-8 IC101 B-9 IC102 D-8 IC203 D-5 IC301 G-5 Q101 D-9 Q102 C-10 Q103 B-10 Q104 A-10 Q116 D-10 Q201 D-4 Q202 E-4 Q205 F-4 Q206 D-4 Q209 E-8 Q210 E-9 Q301 F-5 Q302 F-6 Q305 H-6 Q306 G-7 Q308 H-7 Q309 H-7 Q310 G-8 Q311 G-7 Q312 G-7 Q313 H-7 Q314 G-6 ZD103 E-9 ZD302 H-7 ZD304 H-6 ZD305 G-7 (Page 18) (Page 18) (Page 17) (Page 18) (Page 21) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com HCD-E301 17 17 6-5. PRINTED WIRING BOARD – CASSETTE Board – • See page 13 for Circuit Boards Location. 6-6. SCHEMATIC DIAGRAM – CASSETTE Board – • See page 21 for Waveforms. • See page 22 for IC Block Diagram. • Voltages and waveforms are dc with respect to ground under no-signal conditions. no mark : TAPE PLAY ( ) : RECORD (ISS 1) [ ] : RECORD (ISS 2) IC701 + A K + + + + + + + + + + + B C E E C B E C B B C E E C B E C B + A K HPRE701 REC/PB/ERASE HEAD –1 –2 –3 –4 –5 –6 SW701 (REC/PB) REC PB CASSETTE BOARD B MAIN BOARD CN201 A B C 1 2 3 4 5 • Semiconductor Location Ref. No. Location D701 B-4 D702 B-4 IC701 B-3 Q701 A-4 Q702 B-4 Q703 B-4 Q704 A-2 Q705 B-2 Q706 C-2 1 2 3 3 MAIN BOARD (2/2) CN201 B IC B/D 1 9 0 1.2 1.4 3.9 0 0 7.8 7.7 0 3.9 1.4 1.2 0 0 (0.7) 0 0 (0.7) 0 0 (3.5) 0.7 (0) 0.7 0 9.3 (0.8) 9.3 (0.8) 8.9 (0.3) 0.4 (0) [21.4] 0 (0.7)[0] R-CH L-CH ERASE HRPE701 RECORDE/PLAYBACK ERASE CN701 4P 0.0015 0.0015 SW701 (4/6) (REC/PB) REC R PB SW701 (2/6) (REC/PB) REC r PB SW701 (3/6) (REC/PB) REC t PB Q705 ISS SWITCHING 0.0027 0.022 0.022 + 50V 0.022 0.0068 Q706 REC BIAS OSC SW701 (6/6) (REC/PB) REC T PB MUTING CONTROL SWITCH Q704 REC ON SWITCH 25V + 1SS133T -77 + + 50V 5.6k 1.2k 0.1 SW701 (1/6) (REC/PB) REC R PB 0.1 50V + + 0.022 10V + + 0.1 50V + + 0.1 5.6k 1.2k IN1 NF1 PC1 OUT1 GND IN2 NF2 PC2 OUT2 VCC ALC IN1 ALC CONST ALC IN2 RF SW701 (5/6) (REC/PB) REC r PB 50V + IC701 ALC, REC/PB AMP Q701, 702 MUTING 50V 50V + + CASSETTE BOARD 0.0018 0.0018 330 2SD1616-L 50V 100k 1N4148TP 4.7k (Page 16) (Page 15) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com HCD-E301 18 18 DISPLAY BOARD 1 36 1 3 + MEGA BASS MUSIC MENU SW614 SW631 (MONO STEREO) ST t MONO ISS + – VOLUME 2 t 1 Z PUSH OPEN/CLOSE SW600 A A A A K K A TUNER TAPE REPEAT SW613 K K K K A K A K A K A + SW622 SW621 K K A A A + – TUNING M > m . + – x PRESET SHUFFLE SW608 u SW610 TUNER MEM ENTER PGM + REMAIN CD K K A K K A SW601 – 615 MAIN BOARD CN101 + + A E C B E C B I/1 1 3 TIMER D619 20 1 80 40 41 21 61 60 IC601 D621 LIQUID CRYSTAL DISPLAY IC603 REM601 (INCLUDED IN DISPLAY BOARD) D11 – 19 (LCD BACK LIGHT) D19 D18 R421 R420 D17 D16 D15 D14 D12 D13 D11 R419 1 2 9 8 1 16 IC602 C MAIN BOARD CN302 D MAIN BOARD CN204 A 2 1 A B C D E F 1 2 3 4 5 6 7 6-7. PRINTED WIRING BOARD – DISPLAY Board – • See page 13 for Circuit Boards Location. • Semiconductor Location Ref. No. Location D11 F-4 D12 F-4 D13 F-4 D14 F-4 D15 F-3 D16 F-3 D17 F-3 D18 F-2 D19 F-2 D601 C-6 D602 D-5 D604 C-3 D607 B-3 D608 B-3 D609 D-2 D610 D-2 D611 D-2 D612 C-3 D613 D-3 D614 D-3 D615 D-3 D616 D-6 D617 E-2 D619 B-6 D647 C-6 IC601 B-4 IC602 D-2 IC603 A-3 Q601 B-6 Q602 B-6 REM601 B-6 (Page 16) (Page 16) (Page 16) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com HCD-E301 19 19 MAIN BOARD (2/2) CN204 D MAIN BOARD (2/2) CN302 C MAIN BOARD (1/2) CN101 A 1 2.4 2.4 2.4 2.4 2.4 2.4 4.7 4.7 3.2 1.6 0 (4.7)[4.7] 0 (4)[0] 1.4 (0)[1.4] 4.6 4.6 4.5 0 5.3 5.2 4.7 5.3 5.2 5.3 5.2 0 {3.5} 0 0 0 4.7 MEGA BASS ON : 0.1 OFF : 4.7 0 4.7 4.7 2.4 2.9 5.2 4.6 4.3 5.2 5.2 5.2 5.2 5.6 2.4 2.4 2.4 2.4 2.4 2.4 2.4 2.4 2.4 2.4 2.4 2.4 5.2 5.2 4.7 5.2 0.6 0.6 5.3 5.3 5.3 5.3 4.7 5.3 5.3 5.3 5.3 5.3 5.3 5.3 5.6 5.6 SEL2215S-CD D619 TIMER LIQUID CRYSTAL DISPLAY µPD753016AGC-F31-3B9 IC601 SYSTEM CONTROLLER, LIQUID CRYSTAL DISPLAY DRIVER COM0 S31 S30 S29 S28 S27 S26 S25 S24 S23 S22 S21 S20 S19 S18 S17 S16 S15 S14 S13 S12 COM1 COM2 COM3 BIAS VLC0 VLC1 VLC2 TUNER TAPE CD TIMER STATUS VSS CD RESET SURROUND PLL CL PLL DI TUNER SD CLOCK DATA S11 S10 S9 S8 S7 S6 S5 S4 S3 S2 S1 S0 CPU RESET KEY R3 KEY R2 KEY R1 KEY R0 12/24H SELECT NC CD DATA PLLDO SELECT X2 X1 IC XT2 XT1 VDD DPSW2/SLEND BASS BOOST PSW RDS DATA SHRST CE PLLCE MUTE SYNCRO REMOTE RDS CLOCK CD CLOCK STEREO 1.8k 1.8k BUFFER + + 0.1 0.1 + 10V Q602 POWER ON/OFF SWITCH REM601 REMOTE CONTROL RECEIVER REM601 RPM6938 10V + 0.1 IC602 KEY CONTROL L934SGC/B D11-19 (LCD BACK LIGHT) SW601 SW612 SW613 SW611 SW608 SW610 SW622 SW621 SW605 SW606 SW602 SW604 SW607 MEGA BASS SW615 I /1 TAPE TUNER REMAIN CD x + G O I 16V 0.022 u REPEAT SW603 SHUFFLE MUSIC MENU SW614 TUNER MEM ENTER PGM TUNING + M > SW609 TUNING – . m SW605 SW606 – + PRESET SW621 SW622 – + VOLUME IC603 RESET SIGNAL GENERATOR IC603 P5290 L934SGC/B L934SGC/B L934SGC/B L934SGC/B L934SGC/B L934SGC/B L934SGC/B L934SGC/B 1N4148TP 1N4148TP 1N4148TP 1N4148TP 1N4148TP 1N4148TP 1N4148TP ZPUSH OPEN/CLOSE SW600 DISPLAY BOARD D604 1N4148AP D616 1N4148TP 1N4148TP 1N4148TP 1N4148TP 1N4148TP 1N4148TP 0.1 0.1 0.1 (MONO STEREO) ST t MONO ISS 2 t 1 0.1 10 16V 1000 6.3V 1N4148TP 180 180 180 1 9 1 9 1 8 SW631 TC4094BF 6-8. SCHEMATIC DIAGRAM – DISPLAY Board – • See page 21 for Waveform. • Voltages and waveforms are dc with respect to ground under no-signal (detuned) conditions. no mark : TUNER (FM/AM) ( ) : CD PLAY [ ] : TAPE PLAY { } : RECORD (Page 14) (Page 15) (Page 15) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com HCD-E301 20 20 6-9. SCHEMATIC DIAGRAM – POWER Board – • Voltages are dc with respect to ground under no-signal conditions. no mark : TUNER (FM/AM) 6.2 6.7 7.9 0.6 0 0.5 1.1 1.1 0.7 1.1 MAIN BOARD (2/2) CN304 E CN402 6P B GND + C404 0.022 C402 0.022 + C408 0.022 C406 0.022 TR401 POWER TRANSFORMER MTZJ-6.8B + + + Q404 +6V REGULATOR + Q401–403 POWER ON/OFF RELAY DRIVE TR402 POWER TRANSFORMER 2.2k C421 0.001 250V RL401 AC IN POWER BOARD 2SD1616-L 2SD1616-L 2.2k (Page 15) The components identified by mark 0 or dotted line with mark 0 are critical for safety. Replace only with part number specified. w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com HCD-E301 21 21 4.4 Vp-p 167 ns 0.8 Vp-p 12.4 µs 1.3 Vp-p 12.4 µs 47.2 Vp-p 11.8 µs 3.1 Vp-p 139 ns POWER BOARD + + A K A K K A K A A K A K A A K K A A K K MAIN BOARD K A K A A K A K + + + + B C E B C E E C B B C E AC IN TR402 POWER TRANSFORMER TR401 POWER TRANSFORMER E A B C D E 1 2 3 4 5 6-10. PRINTED WIRING BOARD – POWER Board – • See page 13 for Circuit Boards Location. • Semiconductor Location Ref. No. Location D401 D-1 D402 C-1 D403 D-1 D404 C-1 D405 B-2 D406 C-2 D407 B-2 D408 B-2 D409 C-3 D411 C-3 D412 D-3 D413 C-3 D414 D-3 Q401 B-3 Q402 B-3 Q403 B-3 Q404 B-3 ZD401 B-3 • Waveforms – MAIN Board – 1 IC102 ws (XOUT) – CASSETTE Board – 1 Q705 (Collector) (RECORD (ISS 2) mode) 2 Q706 (Base) (RECORD mode) 3 Q706 (Collector, Emitter) (RECORD mode) – DISPLAY Board – 1 IC601 tl (X2) (Page 16) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com HCD-E301 22 22 RIPPLE FILTER ALC 14 13 12 1 2 3 11 10 9 AMP. CH2 AMP. CH1 8 4 5 6 7 VCC RF ALC IN2 OUT2 PC2 NF2 IN2 GND ALC CONST ALC IN1 OUT1 PC1 NF1 IN1 + – 3 6 9 12 15 2 5 8 11 14 1 4 7 10 13 28 25 22 19 16 29 26 23 20 17 30 27 24 21 18 + – + – + – LATCH DECODER CONTROL SHIFT REGISTER – + LVROUT LVRIN LTOUT LTCOM LT4 LT3 LT2 LT1 L4 L3 L2 L1 VDD CL DI RVROUT RVRIN RTOUT RTCOM RT4 RT3 RT2 RT1 R4 R3 R2 R1 VREF VSS CE 24 23 FM RF 1 AM RF GND2 2 VCC2 REG 3 AM MIX AM OSC OSC BUFFER 4 22 21 VCC1 20 FM OSC PHASE COMP FM MIX DECODER 5 6 19 GND1 7 MUTE 8 18 17 16 9 15 PILOT DET 14 FM DET 13 10 FM S-METER 11 12 ST ST SW FF VCO FF FF TRIG AM IF AM DET AGC FM IF SD IF BUFFER FMRF IN RF GND FMRF OUT VCC2 FM OSC DET OUT MUTE R L AM/FM MO/ST FM DET AMRF IN REG AM OSC VCC1 FM MIX GND FM BUFFER AM OSC BUFFER AM MIX QUAD AMIF SD PHASE DETECTOR CHARGE PUMP SWALLOW COUNTER 1/16, 1/17 4BITS 12BITS PROGRAMMABLE DRIVER UNIVERSAL COUNTER REFERENCE DIVIDER POWER ON RESET 1/2 CCB INTERFACE 1 3 4 5 6 7 8 9 10 18 17 16 15 13 12 11 19 20 21 22 XOUT VSS AOUT AIN PD VDD FMIN AMIN 14 NC XIN DO CL DI CE 2 NC IFIN IO1 BO4 BO3 BO2 BO1 IO2 UNLOCK DETECTOR DATA SHIFT REGISTER LATCH IC102 LC72131 • IC Block Diagrams – MAIN Board – IC101 LA1823 IC203 LC75392 – CASSETTE Board – IC701 AN7312 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 23 HCD-E301 6-11. IC PIN FUNCTION DESCRIPTION • DISPLAY BOARD IC601 µPD753016AGC-F31-3B9 (SYSTEM CONTROLLER, LIQUID CRYSTAL DISPLAY DRIVER) Pin No. Pin Name I/O Description 1 to 20 S12 to S31 O Segment drive signal output to the liquid crystal display (D621) 21 to 24 COM0 to COM3 O Common drive signal output to the liquid crystal display (D621) 25 BIAS O Bias output for the liquid crystal display drive 26 to 28 VLC0 to VLC2 I Input terminal for doubler circuit capacitor connection to develop liquid crystal display drive voltage 29 TUNER O Power on/off control signal output for the tuner section “L”: power on 30 TAPE O Audio line muting on/off control signal output “L”: muting on 31 CD O Power on/off control signal output for the CD section “L”: power on 32 TIMER STATUS O LED drive signal output of the TIMER indicator (D619) “L”: LED on 33 VSS — Ground terminal 34 CD-RESET O Reset signal output to the CD section “L”: reset 35 SURROUND O Not used (pull up) 36 PLL CL O PLL serial data transfer clock signal output to the FM/AM PLL (IC102) 37 PLL DI O PLL serial data output to the FM/AM PLL (IC102) 38 TUNER SD I FM and AM signal meter voltage detection input from the LA1823 (IC101) 39 CLOCK O Serial data transfer clock signal output to the LC75392 (IC203) 40 DATA O Serial data output to the LC75392 (IC203) 41 STEREO I FM stereo detection signal input from the LA1823 (IC101) “L”: stereo 42 CD CLOCK I Serial data transfer clock signal input from the CD section 43 RDS CLOCK I Serial data transfer clock signal input from the RDS decoder Not used (open) 44 REMOTE I Remote control signal input from the remote control receiver (RM601) 45 SYNCRO I Recording on detection signal input 46 MUTE O Audio line muting on/off control signal output “H”: muting on 47 PLLCE O PLL chip enable signal output to the FM/AM PLL (IC102) “H” active 48 CE O Chip enable signal output to the LC75392 (IC203) “H” active 49 SHRST O Not used (open) 50 RDS DATA I Serial data input from the RDS decoder Not used (open) 51 PSW O System power on/off control signal out “H”: power on 52 BASS BOOST O Mega bass on/off selection signal output “H”: mega bass on 53 DPSW2/SLEND I CD lid open/close detection switch (SW600) input terminal “L”: CD lid is closed 54 VDD — Power supply terminal 55 XT1 I Power failure detection input terminal “L”: power failure, “H”: power on 56 XT2 O Not used (open) 57 IC — Internal connection terminal (connected to power supply) 58 X1 I Main system clock input terminal (6 MHz) 59 X2 O Main system clock output terminal (6 MHz) 60 PLLDO SELECT I PLL serial data input from the FM/AM PLL (IC102) 61 CD DATA I/O Two-way data bus with the CD section 62 NC — Not used (open) 63 12/24H SELECT I Not used (fixed at “H”) 64 to 67 KEY R0 to KEY R4 I Key return signal input from the key matrix “L” input when key pressing 68 CPU RESET I System reset signal input from the reset signal generator (IC603) “L”: reset For several hundreds msec. after the power supply rises, “L” is input, then it changes to “H” 69 to 80 S0 to S11 O Segment drive signal output to the liquid crystal display (D621) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 24 HCD-E301 12 3 5 1 2 11 10 9 8 7 6 #1 #1 #4 #2 #2 #2 #2 #3 #5 Front panel section CD cabinet section #3 #3 #1 TR401 7-1. CABINET SECTION SECTION 7 EXPLODED VIEWS • Items marked “*” are not stocked since they are seldom required for routine service. Some delay should be anticipated when ordering these items. • The mechanical parts with no reference num- ber in the exploded views are not supplied. • Hardware (# mark) list and accessories and packing materials are given in the last of the electrical parts list. NOTE: • -XX and -X mean standardized parts, so they may have some difference from the original one. • Color Indication of Appearance Parts Example: KNOB, BALANCE (WHITE) . . . (RED) ↑ ↑ Parts Color Cabinet's Color Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 1 3-451-162-00 WASHER 2 4-235-952-01 AC CORD HOLDER 3 4-236-194-01 EMBLEM BADGE 5 A-4726-786-A MAIN BOARD, COMPLETE 06 1-555-750-00 CORD, POWER, EURO PLUG 7 4-235-974-01 CAB, ANTENNA COVER 8 1-823-170-11 CORD (WITH CONNECTOR) (FM ANT) 9 4-235-972-01 REAR CABINET 10 4-235-995-01 RUBBER FOOT 11 4-235-944-01 POWER PWB MOUNTING BKT 12 A-4726-715-A POWER BOARD, COMPLETE 0TR401 1-437-463-11 TRANSFORMER, POWER The components identified by mark 0 or dotted line with mark 0 are critical for safety. Replace only with part number specified. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 25 HCD-E301 7-2. FRONT PANEL SECTION-1 Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 51 4-235-953-01 VOL. SWING KNOB 52 4-235-950-01 SWING SHAFT 53 4-235-939-01 VOL. DECORATION RING 54 4-236-068-01 DISPLAY WINDOW 55 4-224-104-41 DAMPER 56 4-236-067-01 CASS LID WINDOW 57 4-236-546-01 CASS LID 58 4-235-940-01 CASS LID BKT 59 4-235-981-01 CASS LID SPRING 60 4-235-941-01 MAIN PWB MOUNTING BKT (A) 61 4-235-942-01 CASS PWB MOUNTING BKT (A) 62 A-4726-711-A CASSETTE BOARD, COMPLETE 63 4-235-947-01 CASS PWB MOUNTING BKT (B) 64 1-796-190-11 DECK, MECH (TAPE) 65 4-235-951-01 VOL. SWING LEVER 66 4-235-989-01 VOLUME KNOB SPRING 67 4-235-954-01 CASS KEY (PAUSE) 68 4-235-955-01 CASS KEY (STOP/EJECT) 69 4-235-956-01 CASS KEY (FF) 70 4-235-957-01 CASS KEY (REW) 71 4-235-958-01 CASS KEY (PLAY) 72 4-235-959-01 CASS KEY (REC) 67 68 69 70 71 72 54 55 56 57 58 59 60 61 62 63 64 65 66 51 52 53 #1 #2 #1 #10 #6 not supplied Front panel section-2 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 26 HCD-E301 Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 7-3. FRONT PANEL SECTION-2 101 4-235-995-01 RUBBER FOOT 102 4-235-975-01 FRONT PANEL 103 A-4726-714-A HEADPHONE BOARD, COMPLETE 104 4-235-968-01 TAPE KEY CAP 105 4-235-946-01 FUNCTION KEY BKT 106 4-235-966-01 CD KEY CAP 107 4-235-967-01 TUNER KEY CAP 108 4-235-963-01 PLAY/STOP KNOB 109 4-235-962-01 SKIP/SEARCH KNOB 110 4-235-943-01 MAIN PWB MOUNTING BKT (B) 111 A-4726-785-A DISPLAY BOARD, COMPLETE 112 4-235-965-01 SLIDE KNOB 113 4-235-961-01 BASS/SELECT KNOB 114 4-235-964-01 PRESET UP/DOWN KNOB 115 4-235-994-01 PANEL FIXING PLATE 116 4-235-960-01 POWER KNOB 113 114 115 102 115 115 103 116 104 106 107 105 109 108 110 111 112 101 #4 #4 #4 #4 #11 not supplied #1 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 27 HCD-E301 7-4. CD CABINET SECTION Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 151 4-235-971-01 PLASTIC COVER 152 4-236-280-01 RUBBER, VIBRATION PROOF (PINK) 153 4-235-991-01 PULLEY SCREW * 154 3-509-138-00 CLAMP, SPRING 156 4-235-948-01 DISC HOLDER BKT 157 1-471-144-11 MAGNET 158 4-236-545-01 CD LID 159 4-236-066-01 CD LID WINDOW 160 4-235-970-01 NSX1 PUSH ROD 161 4-235-990-01 CD EJECT SPRING 162 4-235-982-01 CD LID SPRING 163 4-224-104-41 DAMPER 164 4-235-938-01 CD TRAY 165 4-235-949-01 PU COVER 166 1-796-189-11 MECH, CD 167 4-236-281-01 RUBBER, VIBRATION PROOF (BROWN) SW600 1-692-960-21 SWITCH, PUSH (1 KEY) (OPEN/CLOSE) 151 152 152 153 167 167 154 154 154 154 157 156 164 158 159 160 161 162 165 166 163 #7 #2 #9 #8 #6 SW600 #6 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 28 HCD-E301 SECTION 8 ELECTRICAL PARTS LIST CASSETTE Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark A-4726-711-A CASSETTE BOARD, COMPLETE ************************* < CAPACITOR > C701 1-130-474-00 FILM 0.0018uF 5% 50V C702 1-130-474-00 FILM 0.0018uF 5% 50V C703 1-130-495-00 MYLAR 0.1uF 5% 50V C704 1-130-495-00 MYLAR 0.1uF 5% 50V C705 1-162-286-31 CERAMIC 220PF 10% 50V C706 1-162-286-31 CERAMIC 220PF 10% 50V C707 1-104-665-11 ELECT 100uF 20% 10V C708 1-104-665-11 ELECT 100uF 20% 10V C709 1-164-159-11 CERAMIC 0.1uF 50V C710 1-164-159-11 CERAMIC 0.1uF 50V C711 1-126-964-11 ELECT 10uF 20% 50V C712 1-126-964-11 ELECT 10uF 20% 50V C713 1-126-960-11 ELECT 1uF 20% 50V C714 1-126-960-11 ELECT 1uF 20% 50V C715 1-126-956-11 ELECT 0.1uF 20% 50V C716 1-126-956-11 ELECT 0.1uF 20% 50V C717 1-130-473-00 MYLAR 0.0015uF 5% 50V C718 1-130-473-00 MYLAR 0.0015uF 5% 50V C719 1-126-964-11 ELECT 10uF 20% 50V C720 1-104-664-11 ELECT 47uF 20% 10V C721 1-126-935-11 ELECT 470uF 20% 16V C722 1-161-494-00 CERAMIC 0.022uF 25V C723 1-128-551-11 ELECT 22uF 20% 25V C724 1-161-494-00 CERAMIC 0.022uF 25V C725 1-130-476-00 MYLAR 0.0027uF 5% 50V C726 1-162-288-31 CERAMIC 330PF 10% 50V C727 1-161-494-00 CERAMIC 0.022uF 25V C728 1-126-964-11 ELECT 10uF 20% 50V C729 1-130-487-00 MYLAR 0.022uF 5% 50V C730 1-130-481-00 MYLAR 0.0068uF 5% 50V C731 1-162-282-31 CERAMIC 100PF 10% 50V C732 1-162-282-31 CERAMIC 100PF 10% 50V < CONNECTOR > * CN701 1-695-645-11 PLUG (CONNECTOR) 4P < DIODE > D701 8-719-991-33 DIODE 1N4148TP D702 8-719-991-33 DIODE 1SS133T-77 NOTE: • Due to standardization, replacements in the parts list may be different from the parts speci- fied in the diagrams or the components used on the set. • -XX and -X mean standardized parts, so they may have some difference from the original one. • RESISTORS All resistors are in ohms. METAL: Metal-film resistor. METAL OXIDE: Metal oxide-film resistor. F: nonflammable • Items marked “*” are not stocked since they are seldom required for routine service. Some delay should be anticipated when order- ing these items. • SEMICONDUCTORS In each case, u: µ, for example: uA. . : µA. . uPA. . : µPA. . uPB. . : µPB. . uPC. . : µPC. . uPD. . : µPD. . • CAPACITORS uF: µF • COILS uH: µH The components identified by mark 0 or dotted line with mark 0 are critical for safety. Replace only with part number specified. When indicating parts by reference number, please include the board. < IC > IC701 6-700-579-01 IC AN7312 < TRANSISTOR > Q701 8-729-194-57 TRANSISTOR 2SC945-P Q702 8-729-194-57 TRANSISTOR 2SC945-P Q703 8-729-194-57 TRANSISTOR 2SC945-P Q704 8-729-194-57 TRANSISTOR 2SC945-P Q705 8-729-194-57 TRANSISTOR 2SC945-P Q706 8-729-116-82 TRANSISTOR 2SD1616-L < RESISTOR > R701 1-249-393-11 CARBON 10 5% 1/4W R702 1-249-393-11 CARBON 10 5% 1/4W R703 1-249-434-11 CARBON 27K 5% 1/4W R704 1-249-434-11 CARBON 27K 5% 1/4W R705 1-249-433-11 CARBON 22K 5% 1/4W R706 1-249-433-11 CARBON 22K 5% 1/4W R707 1-249-418-11 CARBON 1.2K 5% 1/4W R708 1-249-418-11 CARBON 1.2K 5% 1/4W R709 1-249-413-11 CARBON 470 5% 1/4W R710 1-249-413-11 CARBON 470 5% 1/4W R711 1-249-438-11 CARBON 56K 5% 1/4W R712 1-249-438-11 CARBON 56K 5% 1/4W R713 1-249-433-11 CARBON 22K 5% 1/4W R714 1-249-433-11 CARBON 22K 5% 1/4W R715 1-249-429-11 CARBON 10K 5% 1/4W R716 1-249-429-11 CARBON 10K 5% 1/4W R719 1-249-426-11 CARBON 5.6K 5% 1/4W R720 1-249-426-11 CARBON 5.6K 5% 1/4W R721 1-249-429-11 CARBON 10K 5% 1/4W R722 1-249-429-11 CARBON 10K 5% 1/4W R723 1-247-893-11 CARBON 390K 5% 1/4W R724 1-249-441-11 CARBON 100K 5% 1/4W R725 1-249-411-11 CARBON 330 5% 1/4W R726 1-249-437-11 CARBON 47K 5% 1/4W R727 1-249-430-11 CARBON 12K 5% 1/4W R728 1-249-437-11 CARBON 47K 5% 1/4W R729 1-249-437-11 CARBON 47K 5% 1/4W R730 1-249-437-11 CARBON 47K 5% 1/4W R731 1-247-847-11 CARBON 4.7K 5% 1/4W R732 1-249-411-11 CARBON 330 5% 1/4W www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 29 HCD-E301 CASSETTE DISPLAY R733 1-249-429-11 CARBON 10K 5% 1/4W R734 1-249-437-11 CARBON 47K 5% 1/4W R735 1-249-435-11 CARBON 33K 5% 1/4W R736 1-249-396-11 CARBON 18 5% 1/4W < SWITCH > SW701 1-786-225-11 SWITCH, PUSH (1 KEY) (REC/PB) < COIL > T701 1-424-875-11 COIL (OSC) ************************************************************** A-4726-785-A DISPLAY BOARD, COMPLETE ************************ 4-235-945-01 LED & REMOTE SENSOR HOLDER 4-235-973-01 LCD REFLECTOR 4-236-071-01 LCD DIFFUSE SHEET 4-236-072-01 LED DIFFUSE SHEET 7-685-534-14 SCREW +BTP 2.6X8 TYPE2 N-S < CAPACITOR > C602 1-126-514-11 ELECT 22uF 20% 10V C605 1-126-916-11 ELECT 1000uF 20% 6.3V C606 1-126-791-11 ELECT 10uF 20% 16V C613 1-102-516-11 CERAMIC 27PF 5% 50V C614 1-102-960-00 CERAMIC 24PF 5% 50V C619 1-164-159-11 CERAMIC 0.1uF 50V C620 1-164-159-11 CERAMIC 0.1uF 50V C621 1-126-382-11 ELECT 100uF 20% 10V C639 1-164-159-11 CERAMIC 0.1uF 50V C652 1-126-791-11 ELECT 10uF 20% 16V C654 1-161-494-00 CERAMIC 0.022uF 25V C664 1-164-159-11 CERAMIC 0.1uF 50V C665 1-164-159-11 CERAMIC 0.1uF 50V C666 1-164-159-11 CERAMIC 0.1uF 50V C667 1-164-159-11 CERAMIC 0.1uF 50V < DIODE/LIQUID CRYSTAL DISPLAY > D11 8-719-085-51 LED L934SGC/B (LCD BACK LIGHT) D12 8-719-085-51 LED L934SGC/B (LCD BACK LIGHT) D13 8-719-085-51 LED L934SGC/B (LCD BACK LIGHT) D14 8-719-085-51 LED L934SGC/B (LCD BACK LIGHT) D15 8-719-085-51 LED L934SGC/B (LCD BACK LIGHT) D16 8-719-085-51 LED L934SGC/B (LCD BACK LIGHT) D17 8-719-085-51 LED L934SGC/B (LCD BACK LIGHT) D18 8-719-085-51 LED L934SGC/B (LCD BACK LIGHT) D19 8-719-085-51 LED L934SGC/B (LCD BACK LIGHT) D601 8-719-991-33 DIODE 1SS133T-77 D602 8-719-991-33 DIODE 1SS133T-77 D604 8-719-991-33 DIODE 1SS133T-77 D607 8-719-991-33 DIODE 1SS133T-77 D608 8-719-991-33 DIODE 1SS133T-77 D609 8-719-991-33 DIODE 1SS133T-77 D610 8-719-991-33 DIODE 1SS133T-77 D611 8-719-991-33 DIODE 1SS133T-77 D612 8-719-991-33 DIODE 1SS133T-77 D613 8-719-991-33 DIODE 1SS133T-77 D614 8-719-991-33 DIODE 1SS133T-77 D615 8-719-991-33 DIODE 1SS133T-77 D616 8-719-991-33 DIODE 1SS133T-77 D617 8-719-991-33 DIODE 1SS133T-77 D619 8-719-062-11 LED SEL2215S-CD (TIMER) D621 1-804-496-11 DISPLAY PANEL, LIQUID CRYSTAL D647 8-719-991-33 DIODE 1SS133T-77 < IC > IC601 6-800-412-01 IC uPD753016AGC-F31-3B9 IC602 8-759-009-22 IC MC14094BF IC603 8-759-971-11 IC PST529D < COIL > L601 1-410-521-11 INDUCTOR 100uH L602 1-410-509-11 INDUCTOR 10uH < TRANSISTOR > Q601 8-729-194-57 TRANSISTOR 2SC945-P Q602 8-729-194-57 TRANSISTOR 2SC945-P < RESISTOR > R419 1-249-408-11 CARBON 180 5% 1/4W R420 1-249-408-11 CARBON 180 5% 1/4W R421 1-249-408-11 CARBON 180 5% 1/4W R600 1-249-437-11 CARBON 47K 5% 1/4W R601 1-249-429-11 CARBON 10K 5% 1/4W R602 1-249-437-11 CARBON 47K 5% 1/4W R603 1-249-420-11 CARBON 1.8K 5% 1/4W R604 1-249-420-11 CARBON 1.8K 5% 1/4W R605 1-249-429-11 CARBON 10K 5% 1/4W R606 1-247-807-31 CARBON 100 5% 1/4W R607 1-249-437-11 CARBON 47K 5% 1/4W R608 1-249-437-11 CARBON 47K 5% 1/4W R609 1-249-437-11 CARBON 47K 5% 1/4W R610 1-249-429-11 CARBON 10K 5% 1/4W R611 1-249-429-11 CARBON 10K 5% 1/4W R612 1-249-429-11 CARBON 10K 5% 1/4W R613 1-249-429-11 CARBON 10K 5% 1/4W R614 1-247-843-11 CARBON 3.3K 5% 1/4W R615 1-249-429-11 CARBON 10K 5% 1/4W R616 1-247-871-11 CARBON 47K 5% 1/4W R618 1-249-433-11 CARBON 22K 5% 1/4W R620 1-249-433-11 CARBON 22K 5% 1/4W R621 1-249-429-11 CARBON 10K 5% 1/4W R623 1-249-417-11 CARBON 1K 5% 1/4W R625 1-249-417-11 CARBON 1K 5% 1/4W R627 1-249-437-11 CARBON 47K 5% 1/4W R628 1-249-417-11 CARBON 1K 5% 1/4W R629 1-249-417-11 CARBON 1K 5% 1/4W R631 1-249-437-11 CARBON 47K 5% 1/4W R632 1-249-437-11 CARBON 47K 5% 1/4W R633 1-249-437-11 CARBON 47K 5% 1/4W R634 1-249-437-11 CARBON 47K 5% 1/4W R636 1-249-437-11 CARBON 47K 5% 1/4W R638 1-249-437-11 CARBON 47K 5% 1/4W R639 1-249-417-11 CARBON 1K 5% 1/4W www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 30 HCD-E301 DISPLAY HEADPHONE MAIN R640 1-249-417-11 CARBON 1K 5% 1/4W R641 1-249-437-11 CARBON 47K 5% 1/4W R642 1-249-433-11 CARBON 22K 5% 1/4W R643 1-249-433-11 CARBON 22K 5% 1/4W R644 1-249-433-11 CARBON 22K 5% 1/4W R645 1-249-437-11 CARBON 47K 5% 1/4W R646 1-249-437-11 CARBON 47K 5% 1/4W R647 1-249-437-11 CARBON 47K 5% 1/4W R657 1-249-409-11 CARBON 220 5% 1/4W R658 1-249-437-11 CARBON 47K 5% 1/4W R663 1-249-429-11 CARBON 10K 5% 1/4W R664 1-249-429-11 CARBON 10K 5% 1/4W R665 1-249-429-11 CARBON 10K 5% 1/4W R667 1-247-871-11 CARBON 47K 5% 1/4W < IC > REM601 8-749-016-29 IC RPM6938 (REMOTE CONTROL RECEIVER) < SWITCH > SW601 1-570-472-11 SWITCH, KEY BOARD (I/1) SW602 1-570-472-11 SWITCH, KEY BOARD (REPEAT) SW603 1-570-472-11 SWITCH, KEY BOARD (SHUFFLE) SW604 1-570-472-11 SWITCH, KEY BOARD (TUNER MEM, ENTER PGM) SW605 1-570-472-11 SWITCH, KEY BOARD (PRESET –) SW606 1-570-472-11 SWITCH, KEY BOARD (PRESET +) SW607 1-570-472-11 SWITCH, KEY BOARD (TUNING +, M >) SW608 1-570-472-11 SWITCH, KEY BOARD (x) SW609 1-570-472-11 SWITCH, KEY BOARD (TUNING –, . m) SW610 1-570-472-11 SWITCH, KEY BOARD (u) SW611 1-570-472-11 SWITCH, KEY BOARD (REMAIN CD) SW612 1-570-472-11 SWITCH, KEY BOARD (TAPE) SW613 1-570-472-11 SWITCH, KEY BOARD (TUNER) SW614 1-570-472-11 SWITCH, KEY BOARD (MUSIC MENU) SW615 1-570-472-11 SWITCH, KEY BOARD (MEGA BASS) SW621 1-554-088-00 SWITCH, KEY BOARD (VOLUME –) SW622 1-554-088-00 SWITCH, KEY BOARD (VOLUME +) SW631 1-786-224-11 SW, SLIDE (MONO STEREO, ISS) < VIBRATOR > X602 1-795-398-11 VIBRATOR, CRYSTAL (6MHz) ************************************************************** A-4726-714-A HEADPHONE BOARD, COMPLETE *************************** < JACK > JK401 1-815-813-11 JACK (LARGE TYPE) (PHONES) < RESISTOR > R412 1-249-408-11 CARBON 180 5% 1/4W R413 1-249-408-11 CARBON 180 5% 1/4W ************************************************************** A-4726-786-A MAIN BOARD, COMPLETE ********************* 1-424-881-11 AM BAR ANT 4-235-969-01 BAR HOLDER 7-682-549-09 SCREW +B 3X10 < TERMINAL > ANT101 1-694-848-11 TERMINAL BOARD (ANT FM) (FM ANT) < CAPACITOR > C102 1-162-282-31 CERAMIC 100PF 10% 50V C104 1-162-294-31 CERAMIC 0.001uF 10% 50V C105 1-162-294-31 CERAMIC 0.001uF 10% 50V C107 1-130-471-00 MYLAR 0.001uF 5% 50V C108 1-126-963-11 ELECT 4.7uF 20% 50V C109 1-102-936-00 CERAMIC 3.0PF 0.25PF 50V C110 1-162-205-31 CERAMIC 18PF 5% 50V C111 1-162-294-31 CERAMIC 0.001uF 10% 50V C112 1-162-294-31 CERAMIC 0.001uF 10% 50V C113 1-130-485-00 MYLAR 0.015uF 5% 50V C114 1-130-485-00 MYLAR 0.015uF 5% 50V C116 1-161-494-00 CERAMIC 0.022uF 25V C117 1-130-477-00 MYLAR 0.0033uF 5% 50V C118 1-130-477-00 MYLAR 0.0033uF 5% 50V C119 1-126-960-11 ELECT 1uF 20% 50V C120 1-126-960-11 ELECT 1uF 20% 50V C121 1-162-290-31 CERAMIC 470PF 10% 50V C122 1-126-957-11 ELECT 0.22uF 20% 50V C123 1-126-959-11 ELECT 0.47uF 20% 50V C124 1-126-960-11 ELECT 1uF 20% 50V C126 1-162-306-11 CERAMIC 0.01uF 30% 16V C127 1-127-884-11 CERAMIC 0.047uF 10% 50V C128 1-126-935-11 ELECT 470uF 20% 16V C129 1-126-963-11 ELECT 4.7uF 20% 50V C130 1-126-964-11 ELECT 10uF 20% 50V C131 1-127-884-11 CERAMIC 0.047uF 10% 50V C135 1-110-342-11 MYLAR 390PF 5% 50V C136 1-102-947-00 CERAMIC 10PF 0.5PF 50V C140 1-127-884-11 CERAMIC 0.047uF 10% 50V C144 1-161-494-00 CERAMIC 0.022uF 25V C145 1-162-282-31 CERAMIC 100PF 10% 50V C146 1-162-294-31 CERAMIC 0.001uF 10% 50V C147 1-162-306-11 CERAMIC 0.01uF 30% 16V C148 1-126-963-11 ELECT 4.7uF 20% 50V C150 1-126-935-11 ELECT 470uF 20% 16V C151 1-127-888-11 CERAMIC 0.1uF 10% 50V C152 1-127-888-11 CERAMIC 0.1uF 10% 50V C153 1-101-974-11 CERAMIC 20PF 5% 50V C154 1-102-518-11 CERAMIC 33PF 5% 50V C155 1-102-518-11 CERAMIC 33PF 5% 50V C156 1-104-664-11 ELECT 47uF 20% 10V C157 1-127-888-11 CERAMIC 0.1uF 10% 50V C160 1-162-191-31 CERAMIC 2.2PF 10% 50V C161 1-127-888-11 CERAMIC 0.1uF 10% 50V C162 1-161-494-00 CERAMIC 0.022uF 25V C163 1-126-933-11 ELECT 100uF 20% 16V C166 1-104-664-11 ELECT 47uF 20% 10V www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 31 HCD-E301 C167 1-162-290-31 CERAMIC 470PF 10% 50V C181 1-102-962-00 CERAMIC 30PF 5% 50V C190 1-102-962-00 CERAMIC 30PF 5% 50V C201 1-127-872-11 CERAMIC 4700PF 10% 50V C202 1-126-935-11 ELECT 470uF 20% 16V C203 1-126-960-11 ELECT 1uF 20% 50V C204 1-126-960-11 ELECT 1uF 20% 50V C205 1-127-888-11 CERAMIC 0.1uF 10% 50V C206 1-127-888-11 CERAMIC 0.1uF 10% 50V C207 1-127-888-11 CERAMIC 0.1uF 10% 50V C208 1-127-888-11 CERAMIC 0.1uF 10% 50V C209 1-127-888-11 CERAMIC 0.1uF 10% 50V C210 1-127-888-11 CERAMIC 0.1uF 10% 50V C211 1-126-963-11 ELECT 4.7uF 20% 50V C212 1-126-963-11 ELECT 4.7uF 20% 50V C213 1-126-961-11 ELECT 2.2uF 20% 50V C214 1-126-961-11 ELECT 2.2uF 20% 50V C215 1-130-478-00 MYLAR 0.0039uF 5% 50V C216 1-130-478-00 MYLAR 0.0039uF 5% 50V C219 1-130-488-00 MYLAR 0.027uF 5% 50V C220 1-130-488-00 MYLAR 0.027uF 5% 50V C221 1-136-293-11 MYLAR 0.0082uF 5% 50V C222 1-136-293-11 MYLAR 0.0082uF 5% 50V C225 1-130-477-00 MYLAR 0.0033uF 5% 50V C226 1-130-477-00 MYLAR 0.0033uF 5% 50V C227 1-162-285-31 CERAMIC 180PF 10% 50V C228 1-162-285-31 CERAMIC 180PF 10% 50V C229 1-130-491-00 MYLAR 0.047uF 5% 50V C230 1-130-491-00 MYLAR 0.047uF 5% 50V C231 1-162-199-31 CERAMIC 10PF 5% 50V C232 1-162-199-31 CERAMIC 10PF 5% 50V C238 1-126-935-11 ELECT 470uF 20% 16V C239 1-126-935-11 ELECT 470uF 20% 16V C240 1-130-475-00 FILM 0.0022uF 5% 50V C241 1-126-963-11 ELECT 4.7uF 20% 50V C242 1-126-963-11 ELECT 4.7uF 20% 50V C245 1-162-294-31 CERAMIC 0.001uF 10% 50V C246 1-162-294-31 CERAMIC 0.001uF 10% 50V C247 1-126-959-11 ELECT 0.47uF 20% 50V C248 1-126-959-11 ELECT 0.47uF 20% 50V C249 1-130-475-00 FILM 0.0022uF 5% 50V C250 1-126-964-11 ELECT 10uF 20% 50V C251 1-130-491-00 FILM 0.047uF 5% 50V C301 1-130-471-00 MYLAR 0.001uF 5% 50V C302 1-130-471-00 MYLAR 0.001uF 5% 50V C303 1-104-660-11 ELECT 47uF 20% 16V C304 1-104-660-11 ELECT 47uF 20% 16V C305 1-130-497-00 MYLAR 0.15uF 5% 50V C306 1-130-497-00 MYLAR 0.15uF 5% 50V C307 1-104-665-11 ELECT 100uF 20% 25V C308 1-104-665-11 ELECT 100uF 20% 25V C309 1-126-767-11 ELECT 1000uF 20% 16V C310 1-126-767-11 ELECT 1000uF 20% 16V C311 1-127-888-11 CERAMIC 0.1uF 10% 50V C313 1-126-941-11 ELECT 470uF 20% 25V C314 1-104-666-11 ELECT 220uF 20% 25V C315 1-126-964-11 ELECT 10uF 20% 50V C317 1-161-494-00 CERAMIC 0.022uF 25V C319 1-126-961-11 ELECT 2.2uF 20% 50V C320 1-126-961-11 ELECT 2.2uF 20% 50V C321 1-126-961-11 ELECT 2.2uF 20% 50V C322 1-126-933-11 ELECT 100uF 20% 16V C323 1-161-494-00 CERAMIC 0.022uF 25V C325 1-126-964-11 ELECT 10uF 20% 50V C326 1-126-933-11 ELECT 100uF 20% 16V C327 1-161-494-00 CERAMIC 0.022uF 25V C328 1-104-664-11 ELECT 47uF 20% 10V C329 1-127-888-11 CERAMIC 0.1uF 10% 50V C330 1-126-933-11 ELECT 100uF 20% 16V C331 1-104-665-11 ELECT 100uF 20% 25V C409 1-126-944-11 ELECT 3300uF 20% 25V < CONNECTOR > * CN101 1-564-710-11 PIN, CONNECTOR (SMALL TYPE) 8P * CN201 1-564-711-11 PIN, CONNECTOR (SMALL TYPE) 9P * CN202 1-695-645-11 PLUG (CONNECTOR) 4P * CN203 1-564-711-11 PIN, CONNECTOR (SMALL TYPE) 9P * CN204 1-564-711-11 PIN, CONNECTOR (SMALL TYPE) 9P * CN301 1-565-731-11 PLUG, CONNECTOR (2.5MM) 5P * CN302 1-564-711-11 PIN, CONNECTOR (SMALL TYPE) 9P < DIODE > D101 8-719-991-33 DIODE 1SS133T-77 D102 8-719-991-33 DIODE 1SS133T-77 D103 8-719-070-77 DIODE SVC201SPA-M1-AC D104 8-719-070-77 DIODE SVC201SPA-M1-AC D105 8-719-085-35 DIODE SVC348T D302 8-719-991-33 DIODE 1SS133T-77 D303 8-719-991-33 DIODE 1SS133T-77 D306 8-719-991-33 DIODE 1SS133T-77 D307 8-719-991-33 DIODE 1SS133T-77 D308 8-719-991-33 DIODE 1SS133T-77 D310 8-719-991-33 DIODE 1SS133T-77 D311 8-719-991-33 DIODE 1SS133T-77 D312 8-719-991-33 DIODE 1SS133T-77 D314 8-719-991-33 DIODE 1SS133T-77 D316 8-719-991-33 DIODE 1SS133T-77 D317 8-719-991-33 DIODE 1SS133T-77 < FILTER > F101 1-760-393-11 FILTER, CERAMIC (10.7MHz) F102 1-795-397-11 FILTER, CERAMIC (450kHz) F103 1-234-704-11 FILTER, BAND PASS (FM) < IC > IC101 6-700-580-01 IC LA1823 IC102 8-759-584-70 IC LC72131 IC203 8-759-473-59 IC LC75392 IC301 8-759-246-03 IC TA8229K < COIL > L101 1-414-142-11 INDUCTOR 1uH L103 1-424-880-11 COIL (FM) L104 1-424-879-11 COIL (FM) L106 1-408-801-21 INDUCTOR 0.22uH MAIN www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 32 HCD-E301 L110 1-424-878-11 COIL (ANT) L143 1-414-142-11 INDUCTOR 1uH L301 1-410-525-11 INDUCTOR 220uH < TRANSISTOR > Q101 8-729-231-82 TRANSISTOR 2SC1923-O Q102 8-729-194-57 TRANSISTOR 2SC945-P Q103 8-729-194-57 TRANSISTOR 2SC945-P Q104 8-729-194-57 TRANSISTOR 2SC945-P Q116 8-729-119-76 TRANSISTOR 2SA1175-HFE Q201 8-729-194-57 TRANSISTOR 2SC945-P Q202 8-729-194-57 TRANSISTOR 2SC945-P Q205 8-729-194-57 TRANSISTOR 2SC945-P Q206 8-729-194-57 TRANSISTOR 2SC945-P Q209 8-729-194-57 TRANSISTOR 2SC945-P Q210 8-729-194-57 TRANSISTOR 2SC945-P Q301 8-729-116-82 TRANSISTOR 2SD1616-L Q302 8-729-116-82 TRANSISTOR 2SD1616-L Q305 8-729-804-25 TRANSISTOR 2SB985-T Q306 8-729-194-57 TRANSISTOR 2SC945-P Q308 8-729-037-08 TRANSISTOR KTD2058Y Q309 8-729-119-76 TRANSISTOR 2SA1175-HFE Q310 8-729-194-57 TRANSISTOR 2SC945-P Q311 8-729-194-57 TRANSISTOR 2SC945-P Q312 8-729-116-82 TRANSISTOR 2SD1616-L Q313 8-729-438-33 TRANSISTOR 2SC1383-R Q314 8-729-194-57 TRANSISTOR 2SC945-P < RESISTOR > R101 1-249-393-11 CARBON 10 5% 1/4W R102 1-249-435-11 CARBON 33K 5% 1/4W R103 1-249-435-11 CARBON 33K 5% 1/4W R104 1-249-418-11 CARBON 1.2K 5% 1/4W R105 1-247-883-00 CARBON 150K 5% 1/4W R107 1-249-421-11 CARBON 2.2K 5% 1/4W R108 1-249-424-11 CARBON 3.9K 5% 1/4W R109 1-249-424-11 CARBON 3.9K 5% 1/4W R112 1-247-843-11 CARBON 3.3K 5% 1/4W R114 1-249-429-11 CARBON 10K 5% 1/4W R115 1-249-437-11 CARBON 47K 5% 1/4W R116 1-249-437-11 CARBON 47K 5% 1/4W R117 1-249-441-11 CARBON 100K 5% 1/4W R118 1-247-843-11 CARBON 3.3K 5% 1/4W R119 1-249-441-11 CARBON 100K 5% 1/4W R120 1-249-429-11 CARBON 10K 5% 1/4W R121 1-249-435-11 CARBON 33K 5% 1/4W R123 1-249-441-11 CARBON 100K 5% 1/4W R124 1-249-429-11 CARBON 10K 5% 1/4W R126 1-249-402-11 CARBON 56 5% 1/4W R131 1-249-441-11 CARBON 100K 5% 1/4W R134 1-249-437-11 CARBON 47K 5% 1/4W R135 1-249-425-11 CARBON 4.7K 5% 1/4W R136 1-249-427-11 CARBON 6.8K 5% 1/4W R139 1-249-410-11 CARBON 270 5% 1/4W R144 1-249-437-11 CARBON 47K 5% 1/4W R145 1-249-425-11 CARBON 4.7K 5% 1/4W R146 1-249-426-11 CARBON 5.6K 5% 1/4W R147 1-249-421-11 CARBON 2.2K 5% 1/4W R148 1-249-426-11 CARBON 5.6K 5% 1/4W R150 1-249-417-11 CARBON 1K 5% 1/4W R151 1-249-410-11 CARBON 270 5% 1/4W R152 1-249-437-11 CARBON 47K 5% 1/4W R155 1-249-441-11 CARBON 100K 5% 1/4W R158 1-249-429-11 CARBON 10K 5% 1/4W R166 1-249-441-11 CARBON 100K 5% 1/4W R167 1-249-429-11 CARBON 10K 5% 1/4W R168 1-249-427-11 CARBON 6.8K 5% 1/4W R201 1-249-409-11 CARBON 220 5% 1/4W R202 1-249-429-11 CARBON 10K 5% 1/4W R203 1-249-441-11 CARBON 100K 5% 1/4W R204 1-249-441-11 CARBON 100K 5% 1/4W R205 1-249-417-11 CARBON 1K 5% 1/4W R206 1-249-417-11 CARBON 1K 5% 1/4W R208 1-249-417-11 CARBON 1K 5% 1/4W R209 1-249-435-11 CARBON 33K 5% 1/4W R210 1-249-424-11 CARBON 3.9K 5% 1/4W R211 1-249-424-11 CARBON 3.9K 5% 1/4W R212 1-249-435-11 CARBON 33K 5% 1/4W R213 1-249-434-11 CARBON 27K 5% 1/4W R214 1-249-434-11 CARBON 27K 5% 1/4W R215 1-249-426-11 CARBON 5.6K 5% 1/4W R216 1-249-426-11 CARBON 5.6K 5% 1/4W R219 1-249-428-11 CARBON 8.2K 5% 1/4W R220 1-249-428-11 CARBON 8.2K 5% 1/4W R223 1-249-429-11 CARBON 10K 5% 1/4W R224 1-249-429-11 CARBON 10K 5% 1/4W R225 1-249-434-11 CARBON 27K 5% 1/4W R226 1-249-434-11 CARBON 27K 5% 1/4W R227 1-249-434-11 CARBON 27K 5% 1/4W R228 1-249-434-11 CARBON 27K 5% 1/4W R229 1-249-433-11 CARBON 22K 5% 1/4W R230 1-249-433-11 CARBON 22K 5% 1/4W R231 1-249-440-11 CARBON 82K 5% 1/4W R232 1-249-440-11 CARBON 82K 5% 1/4W R233 1-249-437-11 CARBON 47K 5% 1/4W R234 1-249-427-11 CARBON 6.8K 5% 1/4W R239 1-249-428-11 CARBON 8.2K 5% 1/4W R240 1-249-428-11 CARBON 8.2K 5% 1/4W R241 1-249-393-11 CARBON 10 5% 1/4W R242 1-247-843-11 CARBON 3.3K 5% 1/4W R243 1-247-843-11 CARBON 3.3K 5% 1/4W R245 1-249-427-11 CARBON 6.8K 5% 1/4W R246 1-249-437-11 CARBON 47K 5% 1/4W R247 1-249-421-11 CARBON 2.2K 5% 1/4W R248 1-249-421-11 CARBON 2.2K 5% 1/4W R249 1-247-843-11 CARBON 3.3K 5% 1/4W R250 1-247-843-11 CARBON 3.3K 5% 1/4W R251 1-249-437-11 CARBON 47K 5% 1/4W R252 1-249-437-11 CARBON 47K 5% 1/4W R253 1-249-441-11 CARBON 100K 5% 1/4W R254 1-249-429-11 CARBON 10K 5% 1/4W R255 1-249-429-11 CARBON 10K 5% 1/4W R256 1-249-429-11 CARBON 10K 5% 1/4W R257 1-249-417-11 CARBON 1K 5% 1/4W MAIN www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 33 HCD-E301 R258 1-247-855-11 CARBON 10K 5% 1/4W R262 1-249-437-11 CARBON 47K 5% 1/4W R263 1-249-437-11 CARBON 47K 5% 1/4W R264 1-249-422-11 CARBON 2.7K 5% 1/4W R265 1-249-422-11 CARBON 2.7K 5% 1/4W R266 1-249-430-11 CARBON 12K 5% 1/4W R267 1-249-430-11 CARBON 12K 5% 1/4W R268 1-249-429-11 CARBON 10K 5% 1/4W R269 1-249-417-11 CARBON 1K 5% 1/4W R301 1-249-437-11 CARBON 47K 5% 1/4W R302 1-249-437-11 CARBON 47K 5% 1/4W R303 1-249-425-11 CARBON 4.7K 5% 1/4W R304 1-249-425-11 CARBON 4.7K 5% 1/4W R308 1-249-410-11 CARBON 270 5% 1/4W R309 1-249-410-11 CARBON 270 5% 1/4W R310 1-249-385-11 CARBON 2.2 5% 1/6W R311 1-249-385-11 CARBON 2.2 5% 1/6W R312 1-249-393-11 CARBON 10 5% 1/4W R313 1-247-791-11 CARBON 22 5% 1/4W R315 1-249-437-11 CARBON 47K 5% 1/4W R316 1-249-417-11 CARBON 1K 5% 1/4W R317 1-247-883-00 CARBON 150K 5% 1/4W R318 1-249-399-11 CARBON 33 5% 1/4W R320 1-249-437-11 CARBON 47K 5% 1/4W R321 1-249-414-11 CARBON 560 5% 1/4W R322 1-249-441-11 CARBON 100K 5% 1/4W R323 1-249-425-11 CARBON 4.7K 5% 1/4W R324 1-249-441-11 CARBON 100K 5% 1/4W R325 1-249-441-11 CARBON 100K 5% 1/4W R327 1-249-416-11 CARBON 820 5% 1/4W R328 1-249-429-11 CARBON 10K 5% 1/4W R329 1-249-409-11 CARBON 220 5% 1/4W R330 1-249-409-11 CARBON 220 5% 1/4W R331 1-249-429-11 CARBON 10K 5% 1/4W R333 1-260-064-11 CARBON 1 5% 1/2W R334 1-249-437-11 CARBON 47K 5% 1/4W R335 1-249-429-11 CARBON 10K 5% 1/4W R336 1-249-429-11 CARBON 10K 5% 1/4W < TERMINAL > SPK301 1-537-238-11 TERMINAL BOARD (SPEAKER) < COIL > T102 1-424-877-11 COIL (AM OSC) T103 1-424-876-11 COIL (AM) < TRIMMER > TC101 1-141-304-21 CAP, TRIMMER 10PF TC102 1-141-227-00 CAP, TRIMMER 20PF < DISCRIMINATOR/VIBRATOR > X101 1-795-396-11 DISCRIMINATOR, CERAMIC (10.7MHz) X102 1-577-126-11 VIBRATOR, CRYSTAL (7.2MHz) < DIODE > ZD103 8-719-921-42 DIODE MTZJ-5.1A ZD302 8-719-110-17 DIODE RD10ESB2 ZD304 8-719-110-17 DIODE RD10ESB2 ZD305 8-719-109-93 DIODE RD6.2ESB2 ************************************************************** A-4726-715-A POWER BOARD, COMPLETE *********************** 1-533-217-31 HOLDER, FUSE < CAPACITOR > C402 1-101-005-00 CERAMIC 22000PF 50V C404 1-101-005-00 CERAMIC 22000PF 50V C406 1-101-005-00 CERAMIC 22000PF 50V C408 1-101-005-00 CERAMIC 22000PF 50V C410 1-126-943-11 ELECT 2200uF 20% 25V C415 1-126-935-11 ELECT 470uF 20% 16V C416 1-126-960-11 ELECT 1uF 20% 50V C417 1-126-942-61 ELECT 1000uF 20% 25V C418 1-104-664-11 ELECT 47uF 20% 25V C419 1-104-664-11 ELECT 47uF 20% 25V 0C421 1-113-889-11 CERAMIC 0.001uF 10% 250V < CONNECTOR > * CN402 1-573-457-11 PLUG, CONNECTOR 6P < DIODE > D401 8-719-077-63 DIODE 1N5402 D402 8-719-077-63 DIODE 1N5402 D403 8-719-077-63 DIODE 1N5402 D404 8-719-077-63 DIODE 1N5402 D405 8-719-200-02 DIODE 10E2 D406 8-719-200-02 DIODE 10E2 D407 8-719-200-02 DIODE 10E2 D408 8-719-200-02 DIODE 10E2 D409 8-719-991-33 DIODE 1SS133T-77 D411 8-719-200-02 DIODE 10E2 D412 8-719-200-02 DIODE 10E2 D413 8-719-200-02 DIODE 10E2 D414 8-719-200-02 DIODE 10E2 < FUSE > 0F401 1-533-470- FUSE, GLASS TUBE (DIA. 5) (T3.15AL/250V) 0F402 1-533-468- FUSE, GLASS TUBE (DIA. 5) (T2AL/250V) < TRANSISTOR > Q401 8-729-820-24 TRANSISTOR 2SC3330-T Q402 8-729-116-82 TRANSISTOR 2SD1616-L Q403 8-729-119-76 TRANSISTOR 2SA1175-HFE Q404 8-729-116-82 TRANSISTOR 2SD1616-L < RESISTOR > R402 1-247-839-11 CARBON 2.2K 5% 1/4W R403 1-249-441-11 CARBON 100K 5% 1/4W R404 1-249-393-11 CARBON 10 5% 1/4W R405 1-249-421-11 CARBON 2.2K 5% 1/4W R410 1-249-410-11 CARBON 270 5% 1/4W R411 1-249-393-11 CARBON 10 5% 1/4W 0R412 1-216-478-11 METAL OXIDE 390 5% 3W F The components identified by mark 0 or dotted line with mark 0 are critical for safety. Replace only with part number specified. MAIN POWER www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 34 HCD-E301 < RELAY > 0RL401 1-755-446-11 RELAY < TRANSFORMER > 0TR402 1-437-462-11 TRANSFORMER, POWER < DIODE > ZD401 8-719-109-97 DIODE RD6.8ES-B2 ************************************************************** MISCELLANEOUS ************** 06 1-555-750-00 CORD, POWER 8 1-823-170-11 CORD (WITH CONNECTOR) (FM ANT) 64 1-796-190-11 DECK, MECH 157 1-471-144-11 MAGNET 166 1-796-189-11 MECH, CD SW600 1-692-960-21 SWITCH, PUSH (1 KEY) (OPEN/CLOSE) 0TR401 1-437-463-11 TRANSFORMER, POWER ************************************************************ ************** HARDWARE LIST ************** #1 7-685-534-14 SCREW +BTP 2.6X8 TYPE2 N-S #2 7-685-647-14 SCREW +BVTP 3X10 TYPE2 SLIT #3 7-682-246-04 SCREW +K 3X5 #4 7-685-535-14 SCREW +BTP 2.6X10 TYPE2 N-S #5 7-685-648-14 SCREW +BVTP 3X12 TYPE2 SLIT #6 7-685-504-19 SCREW +BTP 2X6 TYPE2 N-S #7 7-623-916-21 FIBER WASHER 3.3, SMALL #8 7-685-233-19 SCREW +KTP 2.6X6 TYPE2NON-SLIT #9 7-624-106-04 STOP RING 3.0, TYPE -E #10 7-685-533-19 SCREW +BTP 2.6X6 TYPE2 N-S #11 7-685-135-19 SCREW (+ PTPWH) (2.6X10) The components identified by mark 0 or dotted line with mark 0 are critical for safety. Replace only with part number specified. POWER www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 35 HCD-E301 MEMO www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com HCD-E301 REVISION HISTORY Clicking the version allows you to jump to the revised page. Also, clicking the version at the upper right on the revised page allows you to jump to the next revised page. Ver. Date Description of Revision 1.0 2001.05 New www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com
