AEP Model UK Model E Model Tourist Model SERVICE MANUAL COMPACT COMPONENT SYSTEM MICROFILM Model Name Using Similar Mechanism NEW CD Mechanism Type CDM50 Optical Pick-Up Type KSS-313A SPECIFICATIONS — Continued on next page — • HCD-101 is the CD PLAYER, TUNER and AMPLIFIER sections in CMT-101. Tuner section Tuning range 2 band model European model: FM : 87.5-108MHz (50kHz step) AM : 522–1,611kHz Other models: FM : 87.5–108MHz (50kHz step) AM : 531–1,602kHz (at 9kHz interval) 530–1,710kHz (at 10kHz interval) 3 band model FM : 87.5–108MHz (50kHz step) MW : 522–1,611kHz (at 9kHz interval) LW : 144–288kHz (at 3kHz interval) Intermediate frequency FM : 10.7MHz AM : 450kHz Aerial terminals FM : 75Ω unbalanced AM : External aerial terminal Timer Quartz lock system Timer setting One-minute step Sleep timer 10–minute step, max. 90minutes CD player section System Compact disc digital audio system Laser Semiconductor laser (λ=780nm) Laser output power Less than 44.6µW* * This output is the value measured at a distance of 200mm from the objective lens surface on the optical pick-up block with 7mm aperture. Frequency response 5Hz–20kHz Signal to noise ratio More than 90dB Harmonic distortion Less than 0.05% Amplifier section European model: DIN power output 15+15 W (4Ω at 1kHz, DIN Continuous RMS power output 21+21 W (4Ω at 1kHz, 10% THD) Music power output 26+26 W Other model Rated RMS power output 16+16 W (4Ω at 1kHz, 1% THD, AC240V/AC120V) Reference RMS power output 22+22 W (4Ω at 1kHz, 10% THD, AC240V/AC120V) Inputs VIDEO/PC IN jack : Stereo phone jack, sensitivity 500mV, impedance 47kΩ www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com — 2 — SAFETY-RELATED COMPONENT WARNING!! COMPONENTS IDENTIFIED BY MARK ! OR DOTTED LINE WITH MARK ! ON THE SCHEMATIC DIAGRAMS AND IN THE PARTS LIST ARE CRITICAL TO SAFE OPERATION. REPLACE THESE COMPONENTS WITH SONY PARTS WHOSE PART NUMBERS APPEAR AS SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUBLISHED BY SONY. TABLE OF CONTENTS 1. GENERAL ······································································ 3 2. DISASSEMBLY 2-1. Case ···················································································· 4 2-2. Front Panel Section ···························································· 4 2-3. PRE Board ·········································································· 5 2-4. Function board, Relay board, SP TM board, Trans board, Power board········································································ 5 2-5. Mechanism Deck ································································ 6 2-6. Chassis (T2) Assy ······························································· 6 2-7. BD Board············································································ 7 2-8. Roller Arm Block Assy······················································· 7 2-9. Chassis (OPT), Chucking Arm Assy ·································· 8 2-10. Motor (SL) Assy (M102), Optical Pick-Up························ 8 3. TEST MODE ·································································· 9 4. ELECTRICAL ADJUSTMENT ······························ 11 5. DIAGRAMS 5-1. Circuit Boards Location ··················································· 14 5-2. Block Diagram ································································· 15 5-3. Schematic Diagram –BD Section– ··································· 18 5-4. Printed Wiring Board –BD Section– ································ 21 5-5. Printed Wiring Board –Panel Section– ····························· 23 5-6. Schematic Diagram –Panel Section – ······························ 25 5-7. Printed Wiring Board –PRE Section– ······························ 27 5-8. Schematic Diagram –PRE Section– ································· 29 5-9. Printed Wiring Board –Function Section– ······················· 31 5-10. Schematic Diagram –Function Section– ·························· 33 5-11. Printed Wiring Board –Power Section– ··························· 36 5-12. Schematic Diagram –Power Section– ······························ 39 5-13. IC Pin Function ································································ 42 5-14. IC Block Diagrams ··························································· 44 6. EXPLODED VIEWS 6-1. Front Panel Section ·························································· 47 6-2. Chassis Section ································································· 48 6-3. Mechanism Deck Section-1 (CDM50) ····························· 49 6-4. Mechanism Deck Section-2 (CDM50) ····························· 50 7. ELECTRICAL PARTS LIST ··································· 51 Outputs VIDEO/PC OUT jack : Stereo phone jack, 250mV, 1kΩ DIGITAL OUT (CD OPTICAL OUT): Square optical connector jack, –18dBm, wave jength 660nm PHONES (headphones) jack : Stereo mini jack, accepts head phones of 8Ω or more. General Power requirements European model 220–230V AC, 50/60Hz Other models 110–120V or 220–240V AC, 50/60Hz adjustable with voltage selector Power consumption 66W (when connected to TC-TX101, MDS-MX101) Dimensions Approx. 142×125×260mm (w/h/d) incl. projecting parts and controls Mass Approx. 4.1kg NOTES ON HANDLING THE OPTICAL PICK-UP BLOCK OR BASE UNIT The laser diode in the optical pick-up block may suffer electrostatic break-down because of the potential difference generated by the charged electrostatic load, etc. on clothing and the human body. During repair, pay attention to electrostatic break-down and also use the procedure in the printed matter which is included in the repair parts. The flexible board is easily damaged and should be handled with care. NOTES ON LASER DIODE EMISSION CHECK The laser beam on this model is concentrated so as to be focused on the disc reflective surface by the objective lens in the optical pick- up block. Therefore, when checking the laser diode emission, observe from more than 30 cm away from the objective lens. Notes on chip component replacement • Never reuse a disconnected chip component. • Notice that the minus side of a tantalum capacitor may be damaged by heat. Flexible Circuit Board Repairing • Keep the temperature of soldering iron around 270 ˚C during repairing. • Do not touch the soldering iron on the same conductor of the circuit board (within 3 times). • Be careful not to apply force on the conductor when soldering or unsoldering. SERVICE NOTE www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com — 3 — SECTION 1 GENERAL This section is extracted from instruction manual. 1 Remote control signal sensor 2 Power switch 3 CD insertion slot 4 Display window 5 6 (CD EJECT) button 6 PHONES terminal 7 BAND button 8 DBFB button 9 =0/)+ (Cue-up musics, or fast rewind / fast forward) button 0 VOL+/– button !¡ ^ (CD playback or pause) button !™ FUNCTION button !£ p (CD stop) button www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com — 4 — SECTION 2 DISASSEMBLY 2-1. CASE 1 Two screws (Case 3 TP2) 1 Two screws (Case 3 TP2) 2 Remove the case upward in the direction of the arrow. 2-2. FRONT PANEL SECTION 3 Wire (Flat Type) (27 Core) 5 Front panel section 4 Connector (CN916) 1 Two screws (BV/Ring S Tight) 2 Pull the front panel out. claw www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com — 5 — 2-3. PRE board 9 Wire (Flat type) (21 Core) (CN421) 7 Connector (CN107) !™ PRE board !¡ Two Connectors (CN420, CN422) 4 Two screws (BVTP 3×8) 8 CDM50 6 Wire (Flat type) (30 Core) 5 Two screws (BVTT 3×6) 3 Back Panel 2 Connector (CN814) !º Connector (CN423) !£ Remove CN911 6-pin (Posistor board) 1 Four screws (BVTP 3×8) 1 Six screws (BVTP 3×8) 5 Two screws (BVTT 3×6) 2-4. FUNCTION board, RELAY board, SP TM board, TRANS board, POWER board 8 Two screws (BVTT 3×6) 6 Relay board 7 SP TM board !¡ Trans board Power board !º Power cord (CN902) 9 Power board 3 Connector (CN910) Trans board Function board 2 Connector (CN404) 4 Function board 1 Screws (BVTP 3×8) 5 Screws (BVTP 3×8) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com — 6 — 2-5. MECHANISM DECK (CDM50) 3 Mechanism Deck (CDM50) 2 Bracket (CDM) 1 Two screw (BVTT 2.6×6) 1 Two screw (BVTT 2.6×6) 2-6. CHASSIS (T2) ASSY 5 Tension coil spring 3 Four screws (BVTT 3×6) 6 Chassis (T2) assy 1 Two screws (BVTT 2.6×6) 2 Bracket 4 Sensor Flexible board www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com — 7 — 2-7. BD board 3 Flexible board (CN106) 4 Flexible board (CN101) 2 Connectir (CN104) 1 Two screws (BVTT ×2) 5 BD board 2 BELT (L) 1 Spring (press) 3 Roller arm block assy 1 Spring (press) 2-8. ROLLER ARM BLOCK ASSY www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com — 8 — 2-9. CHASSIS (OPT) ASSY, CHUCKING ARM ASSY 6 Move the Chucking arm assy to the position shown in the illustration and move it up. 6 Move the Chucking arm assy to the position shown in the illustration and move it up. 5 Spring (CH) 7 Chucking arm assy 4 Spring (FL2) 1 Move the lever in the direction of arrow (A). A 3 Two Spring (FL) 2 Chassis (OPT) assy 2-10. MOTOR (SL) ASSY (M102), OPTICAL PICK-UP (KSS-313A) A 3 Move the shift (SL) assy in the direction of arrow A remove it from chassis (OPT) and optical Pick-up. 7 Chassis (OPT) assy 4 Screws (+P 1.7×4) 5 Gear (SL Feed) 6 Optical Pick-Up (KSS-313A) 1 Two screws (+BVTT 3×6) 2 Motor (SL)assy (M102) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com — 9 — There are two methods to enter the TEST mode. • How to Enter the Test Mode - 1 Remove the AC power cord from wall outlet, and press [EJECT 6]. While pressing [EJECT 6], connect the AC power cord to wall outlet. • How to Enter the Test Mode - 2 (This method toggles between “Entering the TEST Mode” and “Exiting the TEST Mode”.) Turn on the main power. While pressing [TUNING +], press [DBFB], release hand from [DBFB] then press [FUNCTION]. (Keep pressing [TUNING] all the way.) Pressing these buttons again in the same order exits the TEST mode. * The small ATT segment lights in the center top of display during the TEST mode. * To exit the TEST mode, disconnect the AC power cord from wall outlet, or use “How to Enter the TEST Mode - 2”. 1. Audio volume control setting (Can be adjusted only during TEST mode.) Press [CD STOP p] and [VOL–] at the same time → VOL MINIMUM appears Press [CD STOP p] and [VOL+] at the same time → VOL MAXIMUM appears * The audio volume data is kept stored even after the main power is turned off. 2. Audio balance setting (Can be adjusted only during TEST mode.) Press [CD STOP p] and [DBFB] at the same time → LEFT 10 appears Press [CD STOP p] and [FUNCTION] at the same time → RIGHT 10 appears Press [CD STOP p] and [CD EJECT 6] at the same time → CENTER appears * The audio balance data is kept stored even after the main power is turned off. 3. Key test and FL display tube test (Can be adjusted only during TEST mode.) • Press [VOL-] and [BAND] at the same time→All FL tubes light. Pressing the following key in this status enables key checks as follows. • Display depending upon the pressed key [FUNCTION] → KEY NO. 1 [VOL –] → KEY NO. 2 [VOL +] → KEY NO. 3 [BAND] → KEY NO. 4 [TUNING+] → KEY NO. 5 [EJECT 6] → KEY NO. 6 [TUNING –] → KEY NO. 7 [STOP p] → KEY NO. 8 [PLAY ^] → KEY NO. 9 [DBFB] → KEY NO. 10 • [POWER] → Returns to the TEST mode * Note: After all keys are (KEY No.1 to KEY No.10) tested, CHECK OK!! appears. The following items have no relation with the TEST mode. 4. Initial setting (All clear of all memories) Disconnect the AC power cord. While pressing [POWER], connect the AC power cord to wall outlet. 5. Watch operation check (Can be operated only while the main power is off.) Press [FUNCTION] and [BAND] at the same time. → Watch starts counting. Various CD tests Pressing the two keys at the same time enables the various adjustment and test as follows in the TEST mode, and “ATT” segment is flashing. 1) Pressing [TUNING–] and [CD EJECT 6] at the same time : The present normal tracking balance value (“31” to “36”) is displayed when the above key operation is performed and (TRBAL.) is displayed. The tracking gain is fixed to “3F” (TOG1 to TOG2: all off) 2) Pressing [TUNING–] and [DBFB] at the same time : (SHUFFLE) is displayed. • ADJUSTMENT mode When the above key operation is performed, the machine enters the ADJUSTMENT mode. The “SHUFFLE” flashes on display tube. During the ADJUSTMENT mode: The CLV gain is not switched to 8 cm. (The CLV gain is fixed to 12 cm always.) The machine is ready to enter the AF-ADJUSTMENT mode as described below. 3) Pressing [TUNING–] and [FUNCTION] at the same time : (SHUFFLE) and (PROGRAM) are displayed. • AF-ADJUSTMENT mode After the machine enters the ADJUSTMENT mode by the key operation as described in step 2), the machine can enter the AF-ADJUSTMENT mode by pressing the above key operation. [TUNING – /FUNCTION] The “SHUFFLE” and “PROGRAM” flash on display. During the AF-ADJUSTMENT mode, the tracking and sled servos are turned off in addition to the ADJUSTMENT mode. The machine stops the GFS error check which is normally performed by software. • Sled motor check When disc is removed by pressing EJECT during the AF- ADJUSTMENT mode, the sled can be moved to inner circumference or outer circumference by pressing [TUNING– ] or [TUNING+]. At this time, because the microprocessor is not sensing the sled position, be careful when moving the sled not to damage gears and other mechanism. 4) Pressing [TUNING–] and [VOL–] at the same time : • No CDM mode [1] is displayed. When the above key operation is performed, the control on the slot mechanism which takes in and ejects a CD disc is stopped. At this time “1” on the display flashes. During the no CDM mode, The TOC data is deleted by the [CD EJECT 6] key. (When the TEST mode is cleared and a CD disc is inserted, machine reads the TOC again.) SECTION 3 TEST MODE www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com — 10 — 5) Pressing [TUNING–] and [VOL+] at the same time : • Aging mode The machine enters the aging mode by inserting a CD disc and performing the above button operation. The display starts counting the aging operation with COUNT display, and “REPEAT” flashes. Aging operation 1. Machine takes a disc into the machine. 2. Reads the TOC. 3. Accesses to the last track. 4. Plays back the last 2 seconds. 5. Ejects the disc. The one complete operation from step 1 to step 5 is one count. The cycle is repeated. However, steps 2 to 4 are skipped in all modes other than the CD function. Steps 1 and 5 are skipped in the no CDM mode. The aging operation ends when an error occurs. Aging error display “Load Error” : Loading operation is not completed in four seconds. “Eject Error” : Eject operation is not completed in four seconds. “Q TOC Err” : The Q data could not be read during eight seconds. (During TOC read) “Q SRCH Err” : The Q data could not be read during eight seconds. (During track search) “Q PLAY Err” : The Q data could not be read during eight seconds. (During PLAY) “FOK UP Err” : Focus could not be locked in. (During setup) “FOK TOC Err” : Focus is un-locked many times. (During TOC read) “FOK SRCH Err” : Focus is un-locked many times. (During track search) “FOK PLAY Err” : Focus is un-locked several times. (During play) “GFS UP Err” : GFS error. (During setup) “GFS TOC Err” : GFS error. (During TOC read) “GFS PLAY Err” : GFS error. (During play) Display selection during aging The display can be switched by pressing the [TUNING–] and [FUNCTION] at the same time : Count display Elapsed time display Other errors Normal display Example of display " COUNT 723 " (Machine has repeated for 723 times.) " 12 : 05 : 35 " (12 hours 5 minutes 35 seconds have elapsed.) " TW 2 SW 1 " ** Other troubles “TW*SW*” TW : Numbers of times that the machine could not read TOC. SW : Numbers of times that the machine could not complete the track search within 16 seconds. To exit the aging mode and to return the TEST mode, press [TUNING – ] and [VOL +] at the same time. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com — 11 — CD SECTION Note: 1. CD Block is basically constructed to operate without adjustment. Therefore, check each item in order given. 2. Use YEDS-18 disc (3-702-101-01) unless otherwise indicated. 3. Use the oscilloscope with more than 10MΩ impedance. 4. Clean an object lens by an applicator with neutral detergent when the signal level is low than specified value with the following checks. 5. When optical pickup is replaced during repair, perform the focus bias adjustment. Focus Bias Adjustment This adjustment is to be done when the optical block is replaced. Adjustment procedure: 1. Connect oscilloscope to test point TP (VC) and TP (RF) on BD board. 2. Turned power switch ON. (Stop state) 3. Insert disc (YEDS-18) and press the ^ button. 4. Adjust RV101 so that the oscilloscope waveform is as shown in the figure below (eye pattern). A good eye pattern means that the diamond shape (≈) in the center of the waveform can be clearly distinguished. • RF signal reference waveform (eye pattern) When observing the eye pattern, set the oscilloscope for AC range and raise vertical sensitivity. S-Curve Check Procedure: 1. Connect as oscilloscope to test point TP (VC) and TP (FEO) on BD board. 2. Connect a lead wire between test point TP (FOK) and Ground. 3. Turned Power switch on. 4. Insert disc (YEDS-18) and turned Power switch on again to actuate the focus search. (actuate the focus search when disc table is moving in and out.) 5. Check the oscilloscope waveform (S-curve) is symmetrical between A and B. And confirm that peak to peak level is within 2.4 ± 0.7 Vp-p. S-curve waveform + – BD board TP (RF) TP (VC) oscilloscope (DC range) VOLT/DIV: 200 mV TIME/DIV: 500 ns level: 1.3 ± 0.3Vp-p + – BD board TP (FEO) TP (VC) oscilloscope A B symmetry within 2.4 ± 0.7 Vp-p + – BD board TP (RF) TP (VC) oscilloscope VOLT/DIV: 200 mV TIME/DIV: 500 ns level: 1.3 ± 0.3Vp-p + – BD board TP (TEO) TP (VC) oscilloscope (DC range) SECTION 4 ELECTRICAL ADJUSTMENTS 6. After check, remove the lead wire connected in step 2. Note: • Try to measure several times to make sure that the ratio of A:B or B:A is more than 10:7. • Select a longer sweep time and increase the brightness to obtain best waveform. RF Level Check Procedure: 1. Connect oscilloscope to test point TP (VC) and TP (RF) on BD board. 2. Turned Power switch on. 3. Insert the disc (YEDS-18) and press the ^ button. 4. Confirm that oscilloscope waveform is clear and check RF signal level is correct. Note: Clear RF signal waveform means that the shape “≈” can be clearly distinguished at the center of the waveform. RF signal waveform E-F Balance (Traverse) Check Procedure: 1. Set up the TEST mode step 3) AF-ADJUSTMENT. (see page 9.) 2. Connect as oscilloscope to test point TP (TEO) on BD board. 3. Turned Power switch on. 4. Insert the disc (YEDS-18) in and press the ^ button. 5. Confirm that the oscilloscope waveform is symmetrical on the top and bottom in relation to 0V dc, and check the amplitude. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com — 12 — Focus/Tracking Gain Adjustment This gain has a margin, so even if it is slightly off. There is no problem. Therefore, do not perform, RV102 and RV103 adjustment. Please note that it should be fixed to mechanical center position when you moved and do not know original position. Adjustment Location: [BD BOARD] — Component side — A B 0 V specified value: amplitude: 300 ± 100 mVp-p × 100 = less than ± 7% A-B 2 (A+B) • • A+B = 300 ± 100 mVp-p Traverse waveform symmetry (VC) (RF) (PCK) IC102 IC104 (FOK) (A.GND) (D.GND) (TEO) (TEI) RV101 RV102 RV103 (FEI) (TAO) (FEO) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com — 13 — www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com — 14 — SECTION 5 DIAGRAMS 5-1. CIRCUIT BOARDS LOCATION PRE board POWER IC board POWER board BD board HP board SENSOR board SWITCH board PANEL board VOL SEL board EJECT board FUNCTION board MOTOR board SP TM board RELAY board TRANS board RDS board POSISTOR board www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com HCD-101 5-2. BLOCK DIAGRAM — 15 — — 16 — — 17 — FLUORESCENT INDICATOR TUBE CN410 J402 ANTENNA 1 FM 4 AM 19 ST-R 22 STEREO 21 TUNED 20 MUTE 9 DO 8 CL 6 CE 7 DI 17 ST-L 12 19 L OUT E TB401 TUNER UNIT R-CH J401 VIDEO/ 1 1 CNJ401(1/3) CNJ402(1/3) 5 4 15 14 2 1 15 PD1 11 A 10 B 9 C 3 IC401 INPUT SELECT IC404(1/2) BUFFER IC430 BUFFER DBFB 6 8 9 R-CH 2 1 13 Q401 9V IC422 SURROUND SWITCH REC OUT SWITCH IC402 CONTROL Q421 SURROUND SWITCH 12 14 11 10 35 13 9 A B EFFECT SWITCH IC423 Q424 MUTE MUTE SWITCH Q420,422 Q425 MUTE L IN 18 CK 10 31 RFO 2 R OUT R-CH IC424 VOL LOUDNESS IC801 POWER AMP STAND-BY SWITCH Q802,803 RELAY DRIVE Q804 STAND-BY SWITCH Q801 RY801 + + R-CH R-CH PHONES SPEAKER TM801 J660 2 2 J401(2/3) J402(2/3) TAPE MD OUT STAND-BY SWITCH Q805 DELAY IC802 3 1 D+5.6V POWER ON SWITCH Q821 CUTOFF SWITCH Q820,822 ANA -9V SIN 2 5 F.A IC410 8BIT S/P CONV 6 F.B 7 F.C 16 SURR 14 F.A 15 F.B 9 AUB1 8 AUB2 13 ST POWER 10 CD POWER CK 3 LAT 4 12 POW LD DRIVE Q101,102 A D C B F K B+ OPTICAL PICK-UP BLOCK (KSS313A) LASER ON DIODE VR FOCUS COIL TRACKING COIL 2-AXIS DEVICE FCS+ FCS TRK+ TRK A C B D F E PD LD FOCUS GAIN TRACKING GAIN FOCUS BIAS RV102 RV103 RV101 PD2 36 F 38 E 39 LD 33 PHD 34 FEI 2 TEO 42 TEI 44 FEO 1 23 C OUT 21 DATA 24 SENS 20 XLT 19 CLK 25 FOK 37 FE BIAS 22 IC101 RF AMP, FOCUS/TRACKING, SLED SERVO TRACKING COIL DRIVE FOCUS COIL DRIVE SLED MOTOR DRIVE SPINDLE MOTOR DRIVE FL701 9 R-CH 18 17 12 11 26 27 1 2 M M SLED MOTOR SPINDLE MOTOR SLED M102 M101 14 15 16 19 25 4 7 MOTOR DRIVE TRACKING/FOCS COIL DRIVE SLED/SPINDLE IC102 XRESET TAO 13 FEO 6 FEM 7 SLO 16 TAM 12 SLM 15 IC103 DIGITAL SIGNAL PROCESSOR RF 14 CN IN 55 SE IN 54 FOK 1 DATAO 56 XLTO 57 CLKO 59 MDP 3 SPOD 63 S101 LIMIT SW 21 PCMD 22 BCLK 20 LRCK 34 XTAI 6 XTO DATA 2 BCLK 3 LRCK 1 CKO 4 16 L OUT 13 R OUT 5 XTI 28 MLAT 27 CLOK 26 DATA IC104 DIGITAL FILTER D/A CONVERTER X101 16.9344MHz 51 DATA 53 CLOK 52 XLAT 39 D OUT 11 XRST XRST XRST 50 47 SQCK 43 SCOR 52 SQSO 46 49 SENS STB 12 DATA 11 IC701 SYSTEM CONTROL TA MUTE 47 TA DATA 6 TA CLOCK 7 SP LATCH 8 ST D OUT 3 ST CE 5 ST CLK 4 ST D IN 45 TU MUTE 50 TUNED 43 STEREO 44 2 AU BUS OUT DF LATCH 21 CD DATA 18 CD CLOCK 17 DSP LATCH 20 SQCLK 22 SCOR 36 SUBQ 24 SENS 19 9 7 M LOADING MOTOR M103 2 4 LM2 LOAD IN 49 LOAD OUT 48 X1 12 IC105 LOADING MOTOR DRIVE LM1 X2 11 5MHz X701 TA LATCH 9 39 AU BUS IN 41 SIRCS Q404 8 6 4 5 9 3 AUB CONTROL IC403 FAN DRIVE Q823,824 FAN 8 L L J402(3/3) J401(3/3) 9 11 AUB AC AC 8 9 11 AUB AC AC IC901 CD DIGITAL OUT 3 2 1 AC AC SW+5V 1 3 REMOTE CONTROL RECEIVER IC751 10 RESET Q701 RESET SWITCH 38 AC CUT 27 DISC DET IC850 RESET NON BACK-UP 5V XT1 15 XT2 14 32.76kHz X702 88 80 78 53 . 99 89 100 T0 Q701 BUFFER F1 F2 T1 T11 S0 S34 26 DISC SET 32 KEY0 33 KEY1 S1 DISC SET POWER S2 DISC DET S761 EJECT S755 DBFB S751 VOL S752 VOL + S753 FUNCTION S754 PLAY/ S762 STOP S763 REW/AMS S764 FF/AMS S765 BAND S766 PAUSE LOAD IN 49 LOAD IN 49 PLAY/PAUSE D751 Q921 SWITCH IC933 REG F2 F1 AC AC 3 1 D904 F901 AC IN D903 D902 Malaysia, Singapore, Hong Kong, Tourist MODEL AEP, UK, German MODEL D905 T901 IC932 REG 3 1 IC931 REG 3 1 Q924 SWITCH IC941 REG 3 1 Q931 CD SW+5V Q910,911 SWITCH D901 D703 D704 L701 L901 POW B+ POW B- SW D +5V SW A +5V CDP +7V ST +12V (TUNER) D+5.6V (IC701) NON BACK-UP 5V (IC701) BACK-UP (IC701) ANA +9V ANA -9V D +5V 16 L L L L IN OUT PC FM AM 19 DET 2 16 4 IC601 RDS IC602 BUFFER AEP,German, UK MODEL RDS DATA 42 RDS CLK 37 240V 120V S901 : FM : MD : VIDEO/PC : TAPE SIGNAL PATH : REC : CD : DIGITAL OUT • R-CH : Same as L-CH TAPE MD IN OPTICAL www . x ia o y u 1 6 3 . c o m QQ 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com HCD-101 Pin No. 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 I/O — O O O O O O O O I O I — O I — O O I O O O — I — I I I I I I I I — — I I I I — I — I I I — O O O O Description Power supply (+5V) AU_BUS output Tuner pack (TB401) serial data output Tuner pack (TB401) clock output Tuner pack (TB401) latch output Data output to electronic VOL (IC424) serial-to-parallel conversion IC (IC410) Clock output to electronic VOL (IC424) serial-to-parallel conversion IC (IC410) Latch output to serial-to-parallel conversion IC (IC410) Latch output to electronic VOL (IC424) SYSTEM RESET Main clock oscillator output (5MHz) Main clock oscillator input (5MHz) Connected to Vss Watch oscillator output (32.768 kHz) Watch oscillator input (32.768 kHz) Positive power supply (+5V) CD clock output CD data output CD DSP sense input CD DSP latch output CD D/A latch output CD Sub Q clock output (Not used) Sub Q data input Ground CDM chucking sensor CDM disc sensor CDM disc sensor CDM disc sensor CDM disc sensor Identification input of destination Key input Key input Built-in A/D converter analog power supply (+5V) Built-in A/D converter reference voltage input (+5V) DSP SCOR input DSP clock input AC power off detection AU_BUS input Ground SIRCS remote control input (Not used) Tuner pack (TB401) TUNED input Tuner pack (TB401) STEREO input Tuner pack (TB401) DATA input Positive power supply (+5V) TA mute output CDM 50 load output CDM 50 load input Tuner pack (TB401) mute output Pin Name D+5V AUB OUT ST DATA OUT ST CLOCK ST LATCH TA DATA OUT TA CLOCK LATCH (S.P) LATCH (VOL) RESET X2 X1 D.GND XT2 XT1 D+5V CD CLOCK CD DATA SENSE DSP LATCH DF LATCH SQCLK (OPEN) SUBQ AD.GND DISC SET DISC DET LOAD END DISC IN DISC 8/12 DEST KEY0 KEY 1 AD+5V AD+5V REF SCOR RDS.CLOCK AC.CUT AUB IN D.GND SIRCS RDS.DATA TUNED STEREO ST DATA D+5V TA.MUTE LOAD OUT LOAD IN ST.MUTE Pin No. 51 52 53 54 55 56 57 58 59 60 61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80 81 82 83 84 85 86 87 88 89 90 91 92 93 94 95 96 97 98 99 100 I/O O O O O O O O O O O O O O O O O O O O O O O O O O O O O — O O O O O O O O O O O O O O O O O O O O O Description CD PLAY LED output CD PAUSE LED output FL tube segment output FIP controller pull-down resistor is connected here (–27V) FL tube segment output FL tube grid output Pin Name PLAY LED PAUSE LED S34 S33 S32 S31 S30 S29 S28 S27 S26 S25 S24 S23 S22 S21 S20 S19 S18 S17 S16 S15 S14 S13 S12 S11 S10 S9 VG–27V S8 S7 S6 S5 S4 S3 S2 S1 S0 T11 T10 T9 T8 T7 T6 T5 T4 T3 T2 T1 T0 5-13. IC PIN FUNCTION • IC701 µPD780206GF-023-3BA 5-14. IC BLOCK DIAGRAMS — 42 — — 43 — — 44 — IC 102 BA6397FP 1 2 3 4 7 8 9 10 11 12 13 14 28 27 26 24 22 21 20 19 18 17 DRIVE BUFFER DRIVE BUFFER LEVEL SHIFT LEVEL SHIFT THERMAL SHUT DOWN REGULATOR DRIVER MUTE LEVEL SHIFT DRIVE BUFFER DRIVE BUFFER DRIVE BUFFER DRIVE BUFFER LEVEL SHIFT DRIVE BUFFER DRIVE BUFFER 15 16 23 25 5 6 OUT1A OUT1B IN1A IN1B TR-B REG 0 XRST GND IN2A IN2B OUT2A OUT2B GND OP-OUT GND OUT4A OUT4B IN4A IN4B VC VCC VCC VCC VCC IN3B IN3A OUT3B OUT3A OP+ OP– IC103 CXD2507AQ 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 58 60 61 62 63 64 DIGITAL CLV D/A INTERFACE 16K RAM ERROR CORRECTOR CLOCK GENERATOR 3 6 3 5 14 4 5 57 56 55 54 59 SERVO AUTO SEQUENCER DIGITAL PLL EFM DEMODULATOR CPU INTERFACE SUB CODE PROCESSOR ASYMMETRY CORRECTOR DIGITAL OUT FOK MON MDP MDS LOCK TEST FILO FILI PCO VSS AVSS CLTV AVDD RF BIAS ASYI ASYO ASYE WDCK DATA XRST SENS MUTE SQCK SQSO EXCK SBSO SCOR VSS WFCK EMPH DOUT C4M FSTT XTSL XTAO XTAI MNTO XLON SPOD SPOC SPOB SPOA CLKO VDD XLTO DATO CNIN SEIN CLOK XLAT LRCK PCMD BCLK GTOP XUGF XPCK VDD GFS RFCK CZPO XROF MNT3 MNT1 IC105 LB1638M 1 2 3 4 5 6 7 8 9 10 GND IN1 VCC IN2 GND N.C. OUT2 VS OUT1 N.C. CONTROL LOGIC                                                                             www . x ia o y u 1 6 3 . c o m QQ 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com — 45 — IC104 PCM1710U-B 1 2 3 4 5 6 7 8 9 10 11 12 13 14 27 26 25 24 23 22 21 20 19 18 17 16 15 28 INPUT INTERFACE DIGITAL FILTER NOISE SHAPER 5-LEVEL DAC RIGHT LOW-PASS FILTER RIGHT 3-STAGE AMP RIGHT LOW-PASS FILTER LEFT 3-STAGE AMP LEFT 5-LEVEL DAC LEFT MODE CONTROL TIMING CONTROL LRCIN DIN BCKIN CLKO XTI XTO DGND VDD VCC2R GND2R EXT1R EXT2R VOUTR GND1 ML/DSD MC/DM2 MD/DM1 MUTE MODE CKSL DGND VDD VCC2L VCC1 GND2L EXT1L EXT2L VOUTL IC410 BU2092 2 3 1 4 5 6 7 8 9 17 16 18 15 14 13 12 11 10 VSS DATA CLOCK LCK Q0 Q1 Q2 Q3 Q4 VDD OE Q11 Q10 Q9 Q8 Q7 Q6 Q5 CONTROL CIRCUIT 12-BIT SHIFT REGISTER 12-BIT STORAGE REGISTER OUTPUT BUFFER (OPEN DRAIN) IC941 M5293L 2 5 5k + – 27k OVERCURRENT LIMITTER OVERHEAT PROTECTION REFERENCE VOLTAGE GND ON/OFF IN REFERENCE VOLTAGE OUT 3 4 1 IC424 TC9211P 1 20 2 3 4 5 6 7 8 9 10 19 18 17 16 15 14 13 12 11 OUT IN LD1 L-ch LD2 A-GND NC CS1 GND CK OUT IN LD1 LD2 A-GND NC CS2 STB DATA R-ch VSS VDD L-CH DATA LATCH R-CH DATA LATCH LEVEL SHIFT LEVEL SHIFT SHIFT REGISTER (13-BIT) STROBE GENERATOR www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com — 46 — IC101 CXA1782BQ 36 PHD2 PHD1 PHD 33 LD 32 RF M 31 RF O 30 RF I 29 CP 28 CB 27 CC1 26 CC2 25 FOK 24 SENS 23 C. OUT 22 XRST 21 DATA 20 XLT 19 CLK 18 VCC 17 ISET 16 SL 0 15 SL M 14 SL P 13 12 TA O TA M 11 FSET 10 TG2 9 TGU 8 SRCH 7 FE M 6 FE O 5 FLB 4 FGD 3 FDFCT 2 FEI 1 FEO 48 VC 47 TDFCT 46 TZC 45 ATSC 44 TEI 43 LPFI 42 TEO 41 VEE 40 EI 39 E 38 F 37 FE BIAS + + – + + – + – + – + – + – + – + + + – + – + – + – + – + – + – + – – + + – – + + – + – + – + – + – APC – – – – LEVELS FOK MIRR DFCT RF IV AMP2 RF IV AMP1 FE AMP F IV AMP E IV AMP TE AMP FZC COMP BAL1 BAL2 BAL3 TOG1 TOG2 TOG3 TTL IIL IIL TTL TTL IIL • IIL DATA RESISTOR • INPUT SHIFT RESISTOR • ADDRESS DECODER • OUTPUT DECODER HPF COMP LPF COMP TZC COMP DFCT DFCT TM1 FS4 ATSC • WINDOW COMP • FCS PHASE COMPENSATION • TRACKING • PHASE COMPENSATION • ISET FS1 FS2 TM4 TM5 TM6 TM3 TM7 TG2 • F SET TG1 TM2 + – TOG1-3 FS1-4 TG1-2 TM1-7 PS1-4 BAL1-3 35 34 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com SECTION 6 EXPLODED VIEWS NOTE: • -XX, -X mean standardized parts, so they may have some differences from the original one. • Items marked “*” are not stocked since they are seldom required for routine service. Some delay should be anticipated when ordering these items. • The mechanical parts with no reference number in the exploded views are not supplied. • Hardware (# mark) list is given in the last of this parts list. — 47 — • Abbreviation SP : Singapore MY : Malaysia HK : Hong Kong G : German JE : Tourist 1 4-994-808-01 PANEL (ALUMINUM), FRONT (SP,MY,HK,JE) 1 4-994-808-11 PANEL (ALUMINUM), FRONT (AEP,G,UK) 2 4-942-636-21 EMBLEM (No.3.5), SONY 3 4-994-813-01 FILTER (RM) * 4 1-667-387-11 HP BOARD * 5 4-994-819-31 CASE * 6 A-4403-540-A PANEL BOARD, COMPLETE (SP,MY,HK,JE) * 6 A-4403-560-A PANEL BOARD, COMPLETE (AEP,G) * 6 A-4403-727-A PANEL BOARD, COMPLETE (UK) * 7 1-667-385-11 SWITCH BOARD 8 4-930-336-61 FOOT (FELT) 9 4-958-107-01 SCREW (BV/RING S TIGHT) 10 3-363-099-51 SCREW (CASE 3 TP2) 11 4-951-620-01 SCREW (2.6X8), +BVTP 12 X-4948-993-1 PANEL (M) ASSY 13 1-782-805-11 WIRE (FLAT TYPE) (5 CORE) 14 1-782-781-11 WIRE (FLAT TYPE) (27 CORE) * 15 1-667-388-11 EJECT BOARD Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks 6-1. FRONT PANEL SECTION 10 5 10 11 4 13 15 11 14 11 11 11 6 7 9 12 8 3 1 2 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com — 48 — 51 1-668-138-11 POSISTOR BOARD * 52 1-667-384-11 TRANS BOARD * 53 4-995-817-01 COVER (CABLE) 54 1-782-780-11 WIRE (FLAT TYPE) (21 CORE) * 55 1-667-823-11 POWER IC BOARD * 56 A-4403-527-A PRE BOARD, COMPLETE * 57 4-994-816-01 PANEL, BACK 58 1-698-997-11 FAN, DC * 59 A-4403-536-A FUNCTION BOARD, COMPLETE (SP,MY,HK,JE) * 59 A-4403-553-A FUNCTION BOARD, COMPLETE (AEP,G) * 59 A-4403-726-A FUNCTION BOARD, COMPLETE (UK) 60 4-965-822-01 FOOT * 61 A-4403-537-A POWER BOARD, COMPLETE (SP,MY,HK,JE) * 61 A-4403-555-A POWER BOARD, COMPLETE (AEP,G,UK) * 62 1-667-822-11 RELAY BOARD * 63 1-667-386-11 SP TM BOARD 64 4-985-672-01 SCREW (+PTPWHM2.6), FLOATING !65 1-776-060-11 CORD, POWER (EXCEPT UK) !65 1-776-061-21 CORD, POWER (UK) 66 3-703-244-00 BUSHING (2104), CORD * 67 4-994-825-01 COVER (TR) 68 4-812-134-11 RIVET (DIA. 3.5), NYLON 69 4-889-836-01 CUSHION * 70 1-667-382-11 VOLSEL BOARD * 71 A-4403-559-A RDS BOARD, COMPLETE (AEP,G,UK) !72 1-569-008-11 ADAPTOR, CONVERSION 2P (SP,MY) !73 1-770-019-11 ADAPTOR, CONVERSION PLUG 3P (HK) !T901 1-431-559-11 TRANSFORMER, POWER (AEP,G,UK) !T901 1-431-560-11 TRANSFORMER, POWER (SP,MY,HK,JE) Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks 6-2. CHASSIS SECTION The components identified by mark ! or dotted line with mark ! are critical for safety. Replace only with part number specified. #1 #1 #5 #1 #1 #1 56 53 #1 #1 #5 #1 #1 61 54 55 #5 #4 68 58 #2 #3 T901 #3 64 #5 #3 #5 #5 #5 #3 66 70 71 52 not supplied not supplied not supplied 69 51 59 SP, MY MODEL HK MODEL UK MODEL EXCEPT UK MODEL 73 73 65 65 72 60 not supplied 57 65 63 67 62 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com — 49 — 101 3-387-776-01 BELT (L) 102 3-578-242-11 WASHER 103 3-384-894-01 GEAR (R1) 104 3-384-895-01 GEAR (R2) 105 3-384-900-01 SPRING (PRESS) * 106 X-3366-857-1 ARM ASSY, ROLLER 107 3-384-896-01 GEAR (DOWN) 108 A-3252-591-A GEAR ASSY, ROLLER 109 X-3366-858-4 ARM ASSY, FRICTION 110 3-384-899-01 SPRING (FRICTION) 111 3-384-892-01 BEARING (ROLLER) 112 3-386-150-01 RING (ROLLER), RETAINING 113 3-701-438-11 WASHER, 2.5 114 3-909-408-01 ROLLER (T2) 116 3-384-888-01 SLIDER (L) 117 3-384-887-01 LEVER (L) * 118 X-3371-324-3 CHASSIS (T2) ASSY 119 3-906-923-11 GUIDE (DISK 2) #5 #4 B� � C� � D� � D� � B� � C� � 118 137 S002 122 121 #5 120 127 126 136 123 135 129 128 108 130 131 116 117 107 103 104 113 111 106 105 114 112 111 109 110 119 M103 #8 not supplied not supplied 124 125 103 102 101 102 132 #5 #5 #10 131 120 3-906-921-01 SPRING, TENSION 121 3-906-924-01 SPRING, TENSION * 122 1-653-378-51 SENSOR BOARD 123 3-907-588-11 SPRING (FL2) 124 X-3366-102-1 SLIDER (R) ASSY 125 3-384-889-01 LEVER (R) 126 3-906-939-11 GEAR (RACK 2) * 127 X-3366-853-1 CHASSIS (R) ASSY 128 3-906-940-01 LEVER (ST2) 129 3-384-916-01 SPRING (FL) * 130 X-3373-302-2 CHASSIS (M) ASSY 131 3-384-923-01 SHAFT (DAMPER) * 132 A-4699-821-A BD BOARD, COMPLETE 135 3-384-914-01 DAMPER 136 3-384-914-12 DAMPER 137 1-658-806-11 SENSOR FLEXIBLE BOARD M103 A-3252-580-A MOTOR (L) ASSY (LOADING) S002 1-692-441-11 SWITCH, MICROPHONE (DISC DET) Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks 6-3. MECHANISM DECK SECTION-1 (CDM50) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com — 50 — 151 A-3252-586-A SHAFT (SL) ASSY !152 8-848-283-11 OPTICAL PICK-UP KSS-313A 153 3-384-922-01 GEAR (SL FEED) 154 3-384-920-01 RETAINER (SL FEED) 155 X-3370-190-1 CHASSIS (OPT) ASSY (OUTSERT) * 156 3-384-915-11 BRACKET (CP) * 157 3-384-918-01 RETAINER (DISC) 158 X-3372-948-1 ARM ASSY, CHUCKING 159 3-384-917-01 SPRING (CH) 160 3-926-152-01 SCREW (+PM1.7X2.5) 161 X-3366-100-1 BASE (DRIVING) ASSY 158 160 159 168 156 #4 157 155 161 #5 #5 #9 #6 164 152 162 163 M102 M101 151 167 166 165 153 154 #7 #7 162 3-384-912-11 GEAR (K2) 163 3-570-615-02 POLY-WASHER (DIA.1.2) 164 3-384-913-11 SPRING (THRUST RETAINER) * 165 1-653-379-51 MOTOR BOARD 166 3-918-103-11 SCREW 167 1-653-376-11 MOTOR FLEXIBLE BOARD 168 3-701-442-01 WASHER, POLYETHYLENE M101 X-3367-484-2 MOTOR (SP) ASSY (SPINDLE) M102 A-3252-585-A MOTOR (SL) ASSY (SLED) Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks The components identified by mark ! or dotted line with mark ! are critical for safety. Replace only with part number specified. 6-4. MECHANISM DECK SECTION-2 (CDM50) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com NOTE: • Due to standardization, replacements in the parts list may be different from the parts specified in the diagrams or the components used on the set. • -XX, -X mean standardized parts, so they may have some difference from the original one. • Items marked “*” are not stocked since they are seldom required for routine service. Some delay should be anticipated when ordering these items. • CAPACITORS: uF: µF The components identified by mark ! or dotted line with mark ! are critical for safety. Replace only with part number specified. • RESISTORS All resistors are in ohms. METAL: metal-film resistor METAL OXIDE: Metal Oxide-film resistor F: nonflammable • COILS uH: µH • SEMICONDUCTORS In each case, u: µ, for example: uA...: µA... , uPA... , µPA... , uPB... , µPB... , uPC... , µPC... , uPD..., µPD... When indicating parts by reference number, please include the board name. Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks — 51 — SECTION 7 ELECTRICAL PARTS LIST • Abbreviation SP : Singapore MY : Malaysia HK : Hong Kong G : German JE : Tourist * A-4699-821-A BD BOARD, COMPLETE ******************* 3-934-077-01 CUSHION (LIGHT INTERCEPTION) < CAPACITOR > C101 1-126-607-11 ELECT CHIP 47uF 20% 4V C102 1-163-275-11 CERAMIC CHIP 0.001uF 5% 50V C103 1-164-346-11 CERAMIC CHIP 1uF 16V C105 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V C106 1-164-695-11 CERAMIC CHIP 0.0022uF 5% 50V C107 1-164-695-11 CERAMIC CHIP 0.0022uF 5% 50V C108 1-164-232-11 CERAMIC CHIP 0.01uF 50V C109 1-164-232-11 CERAMIC CHIP 0.01uF 50V C110 1-163-989-11 CERAMIC CHIP 0.033uF 10% 25V C111 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V C112 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V C113 1-164-695-11 CERAMIC CHIP 0.0022uF 5% 50V C114 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V C115 1-126-607-11 ELECT CHIP 47uF 20% 4V C116 1-163-016-00 CERAMIC CHIP 0.0039uF 10% 50V C117 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V C118 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V C119 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V C120 1-135-201-11 TANTALUM CHIP 10uF 20% 4V C121 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V C122 1-164-232-11 CERAMIC CHIP 0.01uF 50V C123 1-164-336-11 CERAMIC CHIP 0.33uF 25V C124 1-126-607-11 ELECT CHIP 47uF 20% 4V C125 1-164-232-11 CERAMIC CHIP 0.01uF 50V C126 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V C127 1-164-695-11 CERAMIC CHIP 0.0022uF 5% 50V C128 1-163-135-00 CERAMIC CHIP 560PF 5% 50V C129 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V C130 1-164-336-11 CERAMIC CHIP 0.33uF 25V C131 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V C132 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V C133 1-163-145-00 CERAMIC CHIP 0.0015uF 5% 50V C134 1-164-346-11 CERAMIC CHIP 1uF 16V C135 1-163-251-11 CERAMIC CHIP 100PF 5% 50V C136 1-164-005-11 CERAMIC CHIP 0.47uF 25V C137 1-164-232-11 CERAMIC CHIP 0.01uF 50V C139 1-163-235-11 CERAMIC CHIP 22PF 5% 50V C140 1-163-235-11 CERAMIC CHIP 22PF 5% 50V C141 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V C142 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V C145 1-135-201-11 TANTALUM CHIP 10uF 20% 4V C146 1-135-201-11 TANTALUM CHIP 10uF 20% 4V C147 1-163-275-11 CERAMIC CHIP 0.001uF 5% 50V C148 1-163-275-11 CERAMIC CHIP 0.001uF 5% 50V C149 1-164-346-11 CERAMIC CHIP 1uF 16V C153 1-124-778-00 ELECT CHIP 22uF 20% 6.3V C154 1-163-235-11 CERAMIC CHIP 22PF 5% 50V C171 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V C172 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V C173 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V C174 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V C175 1-124-778-00 ELECT CHIP 22uF 20% 6.3V C178 1-164-232-11 CERAMIC CHIP 0.01uF 50V C179 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V C180 1-128-065-11 ELECT 68uF 20% 10V C181 1-163-239-11 CERAMIC CHIP 33PF 5% 50V C182 1-163-251-11 CERAMIC CHIP 100PF 5% 50V C183 1-163-251-11 CERAMIC CHIP 100PF 5% 50V C184 1-163-251-11 CERAMIC CHIP 100PF 5% 50V < CONNECTOR > CN101 1-565-728-11 CONNECTOR, FPC 17P CN102 1-770-298-31 HOUSING, CONNECTOR 28P CN104 1-580-055-21 PIN, CONNECTOR 2P CN105 1-774-417-11 CONNECTOR, FPC 5P CN106 1-770-345-21 CONNECTOR, FPC 7P CN107 1-778-638-21 PIN, CONNECTOR (PC BOARD) 2P < FERRITE BEAD > FB101 1-500-245-11 INDUCTOR 0UH FB102 1-216-295-91 CONDUCTOR, CHIP (2012) FB103 1-500-245-11 INDUCTOR 0UH FB104 1-216-295-91 CONDUCTOR, CHIP (2012) FB105 1-414-386-11 INDUCTOR, FERRITE BEAD FB106 1-414-386-11 INDUCTOR, FERRITE BEAD < IC > IC101 8-752-069-56 IC CXA1782BQ IC102 8-759-291-06 IC BA6397FP IC103 8-752-372-94 IC CXD2507AQ IC104 8-759-185-29 IC PCM1710U-B IC105 8-759-823-87 IC LB1638M BD www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks — 52 — < TRANSISTOR > Q1 8-729-032-35 PHOTO TRANSISTOR CPT-230S-C-TU Q2 8-729-032-35 PHOTO TRANSISTOR CPT-230S-C-TU Q4 8-729-032-35 PHOTO TRANSISTOR CPT-230S-C-TU Q101 8-729-010-08 TRANSISTOR MSB710-R Q102 8-729-424-08 TRANSISTOR UN2111 < RESISTOR > R102 1-216-001-00 METAL CHIP 10 5% 1/10W R103 1-216-049-91 METAL GLAZE 1K 5% 1/10W R104 1-216-097-91 METAL GLAZE 100K 5% 1/10W R105 1-216-093-00 METAL CHIP 68K 5% 1/10W R106 1-216-093-00 METAL CHIP 68K 5% 1/10W R107 1-216-093-00 METAL CHIP 68K 5% 1/10W R108 1-216-093-00 METAL CHIP 68K 5% 1/10W R109 1-216-097-91 METAL GLAZE 100K 5% 1/10W R112 1-216-083-00 METAL CHIP 27K 5% 1/10W R113 1-216-083-00 METAL CHIP 27K 5% 1/10W R114 1-216-101-00 METAL CHIP 150K 5% 1/10W R115 1-216-101-00 METAL CHIP 150K 5% 1/10W R116 1-216-061-00 METAL CHIP 3.3K 5% 1/10W R117 1-216-069-00 METAL CHIP 6.8K 5% 1/10W R118 1-216-049-91 METAL GLAZE 1K 5% 1/10W R119 1-216-089-91 METAL GLAZE 47K 5% 1/10W R120 1-216-089-91 METAL GLAZE 47K 5% 1/10W R121 1-216-114-00 METAL GLAZE 510K 5% 1/10W R122 1-216-097-91 METAL GLAZE 100K 5% 1/10W R123 1-216-097-91 METAL GLAZE 100K 5% 1/10W R124 1-216-097-91 METAL GLAZE 100K 5% 1/10W R125 1-216-069-00 METAL CHIP 6.8K 5% 1/10W R126 1-216-061-00 METAL CHIP 3.3K 5% 1/10W R127 1-216-097-91 METAL GLAZE 100K 5% 1/10W R128 1-216-105-91 METAL GLAZE 220K 5% 1/10W R129 1-216-049-91 METAL GLAZE 1K 5% 1/10W R130 1-216-079-00 METAL CHIP 18K 5% 1/10W R131 1-216-079-00 METAL CHIP 18K 5% 1/10W R132 1-216-061-00 METAL CHIP 3.3K 5% 1/10W R133 1-216-061-00 METAL CHIP 3.3K 5% 1/10W R134 1-216-065-00 METAL CHIP 4.7K 5% 1/10W R135 1-216-065-00 METAL CHIP 4.7K 5% 1/10W R136 1-216-073-00 METAL CHIP 10K 5% 1/10W R137 1-216-065-00 METAL CHIP 4.7K 5% 1/10W R138 1-216-049-91 METAL GLAZE 1K 5% 1/10W R139 1-216-033-00 METAL CHIP 220 5% 1/10W R140 1-216-081-00 METAL CHIP 22K 5% 1/10W R141 1-216-061-00 METAL CHIP 3.3K 5% 1/10W R142 1-216-061-00 METAL CHIP 3.3K 5% 1/10W R143 1-216-121-91 METAL GLAZE 1M 5% 1/10W R144 1-216-073-00 METAL CHIP 10K 5% 1/10W R145 1-216-097-91 METAL GLAZE 100K 5% 1/10W R146 1-216-097-91 METAL GLAZE 100K 5% 1/10W R147 1-216-049-91 METAL GLAZE 1K 5% 1/10W R148 1-216-049-91 METAL GLAZE 1K 5% 1/10W R149 1-216-049-91 METAL GLAZE 1K 5% 1/10W R150 1-216-037-00 METAL CHIP 330 5% 1/10W R151 1-216-037-00 METAL CHIP 330 5% 1/10W R152 1-216-037-00 METAL CHIP 330 5% 1/10W R154 1-216-065-00 METAL CHIP 4.7K 5% 1/10W R156 1-216-085-00 METAL CHIP 33K 5% 1/10W R157 1-216-069-00 METAL CHIP 6.8K 5% 1/10W R158 1-216-001-00 METAL CHIP 10 5% 1/10W R171 1-216-049-91 METAL GLAZE 1K 5% 1/10W R172 1-216-049-91 METAL GLAZE 1K 5% 1/10W R173 1-216-049-91 METAL GLAZE 1K 5% 1/10W R174 1-216-049-91 METAL GLAZE 1K 5% 1/10W R175 1-216-049-91 METAL GLAZE 1K 5% 1/10W R176 1-216-049-91 METAL GLAZE 1K 5% 1/10W R177 1-216-049-91 METAL GLAZE 1K 5% 1/10W R183 1-216-105-91 METAL GLAZE 220K 5% 1/10W R184 1-216-105-91 METAL GLAZE 220K 5% 1/10W R185 1-216-105-91 METAL GLAZE 220K 5% 1/10W R186 1-216-295-91 CONDUCTOR, CHIP (2012) R187 1-216-295-91 CONDUCTOR, CHIP (2012) R188 1-216-295-91 CONDUCTOR, CHIP (2012) R189 1-216-295-91 CONDUCTOR, CHIP (2012) < VARIABLE RESISTOR > RV101 1-223-587-11 RES, ADJ, CARBON 22K RV102 1-223-587-11 RES, ADJ, CARBON 22K RV103 1-223-587-11 RES, ADJ, CARBON 22K < SWITCH > S1 1-571-754-31 SWITCH, PUSH (1 KEY) < VIBRATOR > X101 1-767-430-11 VIBRATOR, CRYSTAL 16.9344MHz ************************************************************ * 1-667-388-11 EJECT BOARD *********** < CONNECTOR > CN753 1-580-918-11 HOUSING, CONNECTOR 5P < SWITCH > S755 1-762-875-21 SWITCH, KEYBOARD (6OPEN/CLOSE) ************************************************************ * A-4403-553-A FUNCTION BOARD, COMPLETE (AEP,G) ************************* A-4403-536-A FUNCTION BOARD, COMPLETE (SP,MY,HK,JE) ************************* * A-4403-726-A FUNCTION BOARD, COMPLETE (UK) ************************* < CAPACITOR > C401 1-162-282-31 CERAMIC 100PF 10% 50V (AEP,G,UK) C402 1-126-791-11 ELECT 10uF 20% 35V C403 1-162-282-31 CERAMIC 100PF 10% 50V (AEP,G,UK) C404 1-162-282-31 CERAMIC 100PF 10% 50V (AEP,G,UK) C405 1-162-282-31 CERAMIC 100PF 10% 50V (AEP,G,UK) C406 1-126-791-11 ELECT 10uF 20% 35V BD EJECT FUNCTION www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks — 53 — C407 1-162-282-31 CERAMIC 100PF 10% 50V (AEP,G,UK) C408 1-162-282-31 CERAMIC 100PF 10% 50V (AEP,G,UK) C426 1-164-159-11 CERAMIC 0.1uF 50V C430 1-164-159-11 CERAMIC 0.1uF 50V C431 1-164-159-11 CERAMIC 0.1uF 50V C432 1-126-059-11 ELECT 10uF 20% 50V C433 1-126-059-11 ELECT 10uF 20% 50V C436 1-164-159-11 CERAMIC 0.1uF 50V C437 1-126-934-11 ELECT 220uF 20% 16V C438 1-164-159-11 CERAMIC 0.1uF 50V C450 1-164-159-11 CERAMIC 0.1uF 50V C451 1-161-494-00 CERAMIC 0.022uF 25V C493 1-164-159-11 CERAMIC 0.1uF 50V C501 1-162-282-31 CERAMIC 100PF 10% 50V (AEP,G,UK) C502 1-126-791-11 ELECT 10uF 20% 35V C503 1-162-282-31 CERAMIC 100PF 10% 50V (AEP,G,UK) C504 1-162-282-31 CERAMIC 100PF 10% 50V (AEP,G,UK) C505 1-162-282-31 CERAMIC 100PF 10% 50V (AEP,G,UK) C506 1-126-791-11 ELECT 10uF 20% 35V C507 1-162-282-31 CERAMIC 100PF 10% 50V (AEP,G,UK) C508 1-162-282-31 CERAMIC 100PF 10% 50V (AEP,G,UK) < CONNECTOR > CN401 1-770-406-11 CONNECTOR, BOARD TO BOARD 10P CN402 1-779-968-11 SOCKET, CONNECTOR * CN403 1-774-813-11 CONNECTOR, BOARD TO BOARD 7P(AEP,G,UK) * CN404 1-564-705-11 PIN, CONNECTOR (SMALL TYPE) 3P CN407 1-770-408-11 CONNECTOR, BOARD TO BOARD 14P CN410 1-778-310-11 PLUG, CONNECTOR 2P < JACK > CNJ401 1-770-501-11 JACK 10P (MD) CNJ402 1-770-501-11 JACK 10P (TAPE) < DIODE > D401 8-719-911-19 DIODE 1SS119 D402 8-719-911-19 DIODE 1SS119 D403 8-719-911-19 DIODE 1SS119 D404 8-719-933-39 DIODE HZS6C1L D405 8-719-911-19 DIODE 1SS119 D406 8-719-911-19 DIODE 1SS119 (AEP,G,UK) D407 8-719-911-19 DIODE 1SS119 (AEP,G,UK) D408 8-719-911-19 DIODE 1SS119 (AEP,G,UK) < IC > IC401 8-759-195-14 IC SC027MG051BCP IC402 8-759-195-21 IC SC027MG066BF-T1 IC403 8-759-195-21 IC SC027MG066BF-T1 IC501 8-759-195-14 IC SC027MG051BCP < JACK > J401 1-573-028-31 JACK, PIN 4P (VIDEO/PC(L-IN,L-OUT,R-IN,R-OUT)) J402 1-779-940-11 CONNECTOR, COAXIAL (ANTENNA(AM,FM75 )) < TRANSISTOR > Q401 8-729-422-57 TRANSISTOR UN4111 Q404 8-729-620-05 TRANSISTOR 2SC2603-EF < RESISTOR > R401 1-249-426-11 CARBON 5.6K 5% 1/4W R402 1-249-427-11 CARBON 6.8K 5% 1/4W F R403 1-249-413-11 CARBON 470 5% 1/4W F R404 1-249-441-11 CARBON 100K 5% 1/4W R405 1-249-413-11 CARBON 470 5% 1/4W F R407 1-249-417-11 CARBON 1K 5% 1/4W F R408 1-249-441-11 CARBON 100K 5% 1/4W R409 1-249-409-11 CARBON 220 5% 1/4W F R410 1-249-441-11 CARBON 100K 5% 1/4W R411 1-249-409-11 CARBON 220 5% 1/4W F R412 1-249-441-11 CARBON 100K 5% 1/4W R415 1-249-437-11 CARBON 47K 5% 1/4W R416 1-249-437-11 CARBON 47K 5% 1/4W R417 1-249-437-11 CARBON 47K 5% 1/4W R418 1-249-433-11 CARBON 22K 5% 1/4W R430 1-247-807-31 CARBON 100 5% 1/4W R431 1-249-417-11 CARBON 1K 5% 1/4W F R432 1-249-393-11 CARBON 10 5% 1/4W F R433 1-249-429-11 CARBON 10K 5% 1/4W R434 1-260-095-11 CARBON 470 5% 1/2W R435 1-249-433-11 CARBON 22K 5% 1/4W R436 1-249-433-11 CARBON 22K 5% 1/4W R437 1-247-807-31 CARBON 100 5% 1/4W R438 1-247-807-31 CARBON 100 5% 1/4W R439 1-247-807-31 CARBON 100 5% 1/4W R440 1-247-807-31 CARBON 100 5% 1/4W R441 1-247-807-31 CARBON 100 5% 1/4W R461 1-247-843-11 CARBON 3.3K 5% 1/4W R462 1-249-429-11 CARBON 10K 5% 1/4W R495 1-247-843-11 CARBON 3.3K 5% 1/4W R501 1-249-426-11 CARBON 5.6K 5% 1/4W R502 1-249-427-11 CARBON 6.8K 5% 1/4W F R503 1-249-413-11 CARBON 470 5% 1/4W F R504 1-249-441-11 CARBON 100K 5% 1/4W R505 1-249-413-11 CARBON 470 5% 1/4W F R507 1-249-417-11 CARBON 1K 5% 1/4W F R508 1-249-441-11 CARBON 100K 5% 1/4W R509 1-249-409-11 CARBON 220 5% 1/4W F R510 1-249-441-11 CARBON 100K 5% 1/4W R511 1-249-409-11 CARBON 220 5% 1/4W F R512 1-249-441-11 CARBON 100K 5% 1/4W R561 1-247-843-11 CARBON 3.3K 5% 1/4W R562 1-249-429-11 CARBON 10K 5% 1/4W < TUNER UNIT > TB401 1-233-654-11 ENCAPSULATED COMPONENT (SP,MY,HK,JE) TB401 1-234-028-11 ENCAPSULATED COMPONENT (UK) TB401 1-693-377-11 TUNER (AEP,G) ************************************************************ FUNCTION www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks — 54 — * 1-667-387-11 HP BOARD ********* < CAPACITOR > C491 1-162-294-31 CERAMIC 0.001uF 10% 50V C591 1-162-294-31 CERAMIC 0.001uF 10% 50V < JACK > J660 1-764-106-21 JACK (PHONES) ************************************************************ * 1-653-379-51 MOTOR BOARD ************* < JACK > CNJ303 1-770-348-21 CONNECTOR, FPC 7P < SWITCH > S301 1-571-754-31 SWITCH, PUSH (1 KEY) ************************************************************ * A-4403-540-A PANEL BOARD, COMPLETE (SP,MY,HK,JE) ********************** * A-4403-560-A PANEL BOARD, COMPLETE (AEP,G) ********************** * A-4403-727-A PANEL BOARD, COMPLETE (UK) ********************** * 4-932-810-11 CUSHION (FL) * 4-994-815-01 HOLDER (FL) < CAPACITOR > C701 1-165-319-11 CERAMIC CHIP 0.1uF 50V C702 1-165-319-11 CERAMIC CHIP 0.1uF 50V C703 1-126-157-11 ELECT 10uF 20% 16V C704 1-124-584-00 ELECT 100uF 20% 10V C705 1-104-905-11 CAPACITOR 0.22F 5.5V C706 1-126-157-11 ELECT 10uF 20% 16V C707 1-164-489-11 CERAMIC CHIP 0.22uF 10% 16V C708 1-165-319-11 CERAMIC CHIP 0.1uF 50V C709 1-163-275-11 CERAMIC CHIP 0.001uF 5% 50V C710 1-101-004-00 CERAMIC 0.01uF 50V C711 1-102-958-00 CERAMIC 20PF 5% 50V C712 1-102-958-00 CERAMIC 20PF 5% 50V C713 1-165-319-11 CERAMIC CHIP 0.1uF 50V C715 1-165-319-11 CERAMIC CHIP 0.1uF 50V C716 1-163-251-11 CERAMIC CHIP 100PF 5% 50V C717 1-163-251-11 CERAMIC CHIP 100PF 5% 50V C718 1-163-251-11 CERAMIC CHIP 100PF 5% 50V C719 1-163-251-11 CERAMIC CHIP 100PF 5% 50V C720 1-163-251-11 CERAMIC CHIP 100PF 5% 50V C721 1-163-251-11 CERAMIC CHIP 100PF 5% 50V C722 1-163-251-11 CERAMIC CHIP 100PF 5% 50V C723 1-163-251-11 CERAMIC CHIP 100PF 5% 50V C724 1-163-251-11 CERAMIC CHIP 100PF 5% 50V C725 1-163-251-11 CERAMIC CHIP 100PF 5% 50V C726 1-163-251-11 CERAMIC CHIP 100PF 5% 50V C727 1-163-251-11 CERAMIC CHIP 100PF 5% 50V C728 1-165-319-11 CERAMIC CHIP 0.1uF 50V C729 1-165-319-11 CERAMIC CHIP 0.1uF 50V C730 1-165-319-11 CERAMIC CHIP 0.1uF 50V C731 1-165-319-11 CERAMIC CHIP 0.1uF 50V C751 1-126-154-11 ELECT 47uF 20% 6.3V C752 1-165-319-11 CERAMIC CHIP 0.1uF 50V < CONNECTOR > * CN701 1-568-842-11 SOCKET, CONNECTOR 27P CN702 1-779-970-11 PLUG, CONNECTOR CN703 1-779-938-11 CONNECTOR, BOARD TO BOARD 8P CN752 1-580-918-11 HOUSING, CONNECTOR 5P < DIODE > D701 8-719-016-74 DIODE 1SS352 D702 8-719-016-74 DIODE 1SS352 D703 8-719-210-33 DIODE EC10DS2 D704 8-719-210-33 DIODE EC10DS2 < FILTER > FL701 1-517-701-11 INDICATOR TUBE, FLUORESCENT < IC > IC701 8-759-481-03 IC uPD780206GF-023-3BA IC751 8-759-459-84 IC NJL56H400 (REMOTE SENSOR) IC850 8-759-165-80 IC PST600C-T < COIL > L701 1-412-344-41 INDUCTOR 22uH < TRANSISTOR > Q701 8-729-424-59 TRANSISTOR UN2212 Q704 8-729-421-22 TRANSISTOR UN2211 < RESISTOR > R701 1-216-073-00 METAL CHIP 10K 5% 1/10W R702 1-216-073-00 METAL CHIP 10K 5% 1/10W R704 1-216-073-00 METAL CHIP 10K 5% 1/10W R706 1-216-025-91 METAL GLAZE 100 5% 1/10W R707 1-216-029-00 METAL CHIP 150 5% 1/10W R708 1-216-089-91 METAL GLAZE 47K 5% 1/10W R709 1-216-089-91 METAL GLAZE 47K 5% 1/10W R710 1-216-025-91 METAL GLAZE 100 5% 1/10W R711 1-216-025-91 METAL GLAZE 100 5% 1/10W R712 1-216-025-91 METAL GLAZE 100 5% 1/10W R713 1-216-025-91 METAL GLAZE 100 5% 1/10W R714 1-216-025-91 METAL GLAZE 100 5% 1/10W R715 1-216-025-91 METAL GLAZE 100 5% 1/10W R716 1-216-025-91 METAL GLAZE 100 5% 1/10W R717 1-216-025-91 METAL GLAZE 100 5% 1/10W R718 1-216-025-91 METAL GLAZE 100 5% 1/10W R719 1-216-025-91 METAL GLAZE 100 5% 1/10W R720 1-216-025-91 METAL GLAZE 100 5% 1/10W R721 1-216-017-91 METAL GLAZE 47 5% 1/10W R722 1-216-017-91 METAL GLAZE 47 5% 1/10W HP MOTOR PANEL www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks — 55 — R723 1-216-025-91 METAL GLAZE 100 5% 1/10W R724 1-216-017-91 METAL GLAZE 47 5% 1/10W R725 1-216-017-91 METAL GLAZE 47 5% 1/10W R726 1-216-025-91 METAL GLAZE 100 5% 1/10W R727 1-216-085-00 METAL CHIP 33K 5% 1/10W R728 1-216-085-00 METAL CHIP 33K 5% 1/10W R729 1-216-025-91 METAL GLAZE 100 5% 1/10W R730 1-216-025-91 METAL GLAZE 100 5% 1/10W R731 1-216-025-91 METAL GLAZE 100 5% 1/10W R732 1-216-025-91 METAL GLAZE 100 5% 1/10W R733 1-216-025-91 METAL GLAZE 100 5% 1/10W R734 1-216-073-00 METAL CHIP 10K 5% 1/10W R735 1-216-065-00 METAL CHIP 4.7K 5% 1/10W R736 1-216-073-00 METAL CHIP 10K 5% 1/10W R737 1-216-025-91 METAL GLAZE 100 5% 1/10W R738 1-216-025-91 METAL GLAZE 100 5% 1/10W R739 1-216-025-91 METAL GLAZE 100 5% 1/10W R740 1-216-075-00 METAL CHIP 12K 5% 1/10W (UK) R740 1-216-077-00 METAL CHIP 15K 5% 1/10W (SP,MY,HK,JE) R740 1-216-081-00 METAL CHIP 22K 5% 1/10W (AEP,G) R741 1-216-065-00 METAL CHIP 4.7K 5% 1/10W (SP,MY,HK,JE) R741 1-216-085-00 METAL CHIP 33K 5% 1/10W (AEP,G,UK) R742 1-216-109-00 METAL CHIP 330K 5% 1/10W R743 1-216-041-00 METAL CHIP 470 5% 1/10W R744 1-216-041-00 METAL CHIP 470 5% 1/10W R745 1-216-025-91 METAL GLAZE 100 5% 1/10W R746 1-216-025-91 METAL GLAZE 100 5% 1/10W R755 1-216-065-00 METAL CHIP 4.7K 5% 1/10W R756 1-216-097-91 METAL GLAZE 100K 5% 1/10W R757 1-216-089-91 METAL GLAZE 47K 5% 1/10W R758 1-216-089-91 METAL GLAZE 47K 5% 1/10W R759 1-216-089-91 METAL GLAZE 47K 5% 1/10W R760 1-216-089-91 METAL GLAZE 47K 5% 1/10W R771 1-216-025-91 METAL GLAZE 100 5% 1/10W (AEP,G) R772 1-216-025-91 METAL GLAZE 100 5% 1/10W (SP,MY,HK,JE) R773 1-216-025-91 METAL GLAZE 100 5% 1/10W (UK) < SWITCH > S761 1-762-875-21 SWITCH, KEYBOARD (POWER) < VIBRATOR > X701 1-579-233-11 VIBRATOR, CERAMIC 5MHz X702 1-567-098-41 VIBRATOR, CRYSTAL 32KHz ************************************************************ * 1-668-138-11 POSISTOR BOARD *************** < CAPACITOR > C915 1-164-159-11 CERAMIC 0.1uF 50V C916 1-164-159-11 CERAMIC 0.1uF 50V < CONNECTOR > * CN911 1-564-521-11 PLUG, CONNECTOR < THERMISTOR > THP901 1-801-671-11 THERMISTOR, POSITIVE THP902 1-801-671-11 THERMISTOR, POSITIVE THP903 1-801-671-11 THERMISTOR, POSITIVE THP904 1-801-671-11 THERMISTOR, POSITIVE ************************************************************ * A-4403-537-A POWER BOARD, COMPLETE (SP,MY,HK,JE) *********************** * A-4403-555-A POWER BOARD, COMPLETE (AEP,G,UK) *********************** < CAPACITOR > C801 1-126-043-11 ELECT 0.47uF 20% 50V C803 1-126-868-11 ELECT 47uF 20% 50V C805 1-164-159-11 CERAMIC 0.1uF 50V (AEP,G,UK) C810 1-126-933-11 ELECT 100uF 20% 16V C811 1-126-967-11 ELECT 47uF 20% 50V C851 1-126-043-11 ELECT 0.47uF 20% 50V C853 1-126-868-11 ELECT 47uF 20% 50V C855 1-164-159-11 CERAMIC 0.1uF 50V (AEP,G,UK) C893 1-126-868-11 ELECT 47uF 20% 50V C894 1-126-868-11 ELECT 47uF 20% 50V C901 1-126-029-11 ELECT 3300uF 20% 25V C902 1-126-029-11 ELECT 3300uF 20% 25V C903 1-126-943-11 ELECT 2200uF 20% 25V C905 1-126-376-11 ELECT 470uF 20% 25V C906 1-126-233-11 ELECT 22uF 20% 50V C908 1-136-165-00 FILM 0.1uF 5% 50V C909 1-136-165-00 FILM 0.1uF 5% 50V C911 1-126-868-11 ELECT 47uF 20% 50V C912 1-164-159-11 CERAMIC 0.1uF 50V C914 1-162-306-11 CERAMIC 0.01uF 20% 16V C931 1-126-096-11 ELECT 10uF 20% 35V C932 1-126-096-11 ELECT 10uF 20% 35V C933 1-126-096-11 ELECT 10uF 20% 35V C934 1-126-096-11 ELECT 10uF 20% 35V C935 1-126-096-11 ELECT 10uF 20% 35V C936 1-126-096-11 ELECT 10uF 20% 35V C937 1-164-159-11 CERAMIC 0.1uF 50V C941 1-126-868-11 ELECT 47uF 20% 50V C942 1-164-159-11 CERAMIC 0.1uF 50V C943 1-126-052-11 ELECT 100uF 20% 35V C951 1-164-159-11 CERAMIC 0.1uF 50V C952 1-164-159-11 CERAMIC 0.1uF 50V C960 1-126-025-11 ELECT 330uF 20% 16V C961 1-162-306-11 CERAMIC 0.01uF 20% 16V PANEL POWER POSISTOR www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks — 56 — C962 1-162-306-11 CERAMIC 0.01uF 20% 16V C963 1-162-306-11 CERAMIC 0.01uF 20% 16V C965 1-126-233-11 ELECT 22uF 20% 50V C966 1-164-159-11 CERAMIC 0.1uF 50V C967 1-126-923-11 ELECT 220uF 20% 10V < CONNECTOR > * CN802 1-569-493-11 SOCKET, CONNECTOR 7P * CN806 1-562-334-00 SOCKET, CONNECTOR 10P * CN908 1-506-469-11 PIN, CONNECTOR 4P CN912 1-568-838-11 SOCKET, CONNECTOR 21P * CN913 1-770-656-11 CONNECTOR, FFC/FPC 28P * CN916 1-568-842-11 SOCKET, CONNECTOR 27P * CN917 1-568-951-11 PIN, CONNECTOR 2P < DIODE > D801 8-719-911-19 DIODE 1SS119 D802 8-719-911-19 DIODE 1SS119 D803 8-719-911-19 DIODE 1SS119 D901 8-719-025-03 DIODE RBA-402-SL D902 8-719-200-02 DIODE 10E2 D903 8-719-200-02 DIODE 10E2 D904 8-719-200-82 DIODE 11ES2 D905 8-719-200-82 DIODE 11ES2 D906 8-719-200-82 DIODE 11ES2 D907 8-719-200-82 DIODE 11ES2 D910 8-719-001-79 DIODE UZL-12H1-TP D934 8-719-200-02 DIODE 10E2 D935 8-719-200-02 DIODE 10E2 D936 8-719-200-02 DIODE 10E2 D938 8-719-911-19 DIODE 1SS119 D941 8-719-933-39 DIODE HZS6C1L < TERMINAL > EPT901 1-537-771-21 TERMINAL BOARD, GROUND < IC > IC802 8-759-165-80 IC PST600C-T IC901 8-749-923-04 IC TOTX178 (CD OPTICAL DIGITAL OUT) IC931 8-759-231-53 IC TA7805S IC932 8-759-604-86 IC M5F7807L IC933 8-759-231-53 IC TA7805S IC941 8-759-633-42 IC M5293L < COIL > L901 1-408-413-00 INDUCTOR 22uH L902 1-410-322-11 INDUCTOR 3.3uH < TRANSISTOR > Q801 8-729-900-80 TRANSISTOR DTC114ES Q802 8-729-620-05 TRANSISTOR 2SC2603-EF Q803 8-729-620-05 TRANSISTOR 2SC2603-EF Q804 8-729-620-05 TRANSISTOR 2SC2603-EF Q805 8-729-422-57 TRANSISTOR UN4111 Q910 8-729-202-67 TRANSISTOR 2SK246-GR3 Q911 8-729-021-82 TRANSISTOR 2SD2396K Q931 8-729-140-97 TRANSISTOR 2SB734-34 < RESISTOR > R801 1-249-417-11 CARBON 1K 5% 1/4W F R802 1-247-870-11 CARBON 43K 5% 1/4W R803 1-249-417-11 CARBON 1K 5% 1/4W F R807 1-260-091-11 CARBON 220 5% 1/2W R809 1-249-437-11 CARBON 47K 5% 1/4W R810 1-249-441-11 CARBON 100K 5% 1/4W R811 1-249-441-11 CARBON 100K 5% 1/4W R813 1-249-438-11 CARBON 56K 5% 1/4W !R814 1-219-122-91 FUSIBLE 0.33 5% 1/4W F R841 1-249-441-11 CARBON 100K 5% 1/4W R851 1-249-417-11 CARBON 1K 5% 1/4W F R852 1-247-870-11 CARBON 43K 5% 1/4W R853 1-249-417-11 CARBON 1K 5% 1/4W F R857 1-260-091-11 CARBON 220 5% 1/2W R859 1-249-438-11 CARBON 56K 5% 1/4W !R901 1-208-737-51 FUSIBLE 2.2 5% 1/4W F !R912 1-212-958-00 FUSIBLE 10 5% 1/2W F !R915 1-219-122-91 FUSIBLE 0.33 5% 1/4W F !R916 1-219-122-91 FUSIBLE 0.33 5% 1/4W F R931 1-249-421-11 CARBON 2.2K 5% 1/4W F R932 1-249-409-11 CARBON 220 5% 1/4W F R944 1-249-437-11 CARBON 47K 5% 1/4W R945 1-247-807-31 CARBON 100 5% 1/4W R946 1-247-807-31 CARBON 100 5% 1/4W !R947 1-219-122-91 FUSIBLE 0.33 5% 1/4W F < RELAY > RY801 1-755-126-11 RELAY < THERMISTOR(POSITIVE) > THP801 1-801-829-11 THERMISTOR, POSITIVE ************************************************************ * 1-667-823-11 POWER IC BOARD *************** < CAPACITOR > C807 1-162-219-31 CERAMIC 68PF 5% 50V C831 1-164-159-11 CERAMIC 0.1uF 50V C857 1-162-219-31 CERAMIC 68PF 5% 50V C881 1-164-159-11 CERAMIC 0.1uF 50V < CONNECTOR > * CN805 1-506-608-11 PIN, CONNECTOR 10P < IC > IC801 8-759-333-24 IC LM1876TF < RESISTOR > R804 1-249-437-11 CARBON 47K 5% 1/4W R831 1-249-389-11 CARBON 4.7 5% 1/4W F R854 1-249-437-11 CARBON 47K 5% 1/4W R881 1-249-389-11 CARBON 4.7 5% 1/4W F ************************************************************ POWER POWER IC The components identified by mark ! or dotted line with mark ! are critical for safety. Replace only with part number specified. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks — 57 — * A-4403-527-A PRE BOARD, COMPLETE ******************** < CAPACITOR > C409 1-126-233-11 ELECT 22uF 20% 50V C410 1-126-233-11 ELECT 22uF 20% 50V C411 1-162-207-31 CERAMIC 22PF 5% 50V C412 1-136-177-00 FILM 1uF 5% 50V C413 1-136-177-00 FILM 1uF 5% 50V C414 1-126-961-11 ELECT 2.2uF 20% 50V C415 1-137-364-11 FILM 0.001uF 5% 50V C416 1-136-165-00 FILM 0.1uF 5% 50V C417 1-126-233-11 ELECT 22uF 20% 50V C421 1-126-233-11 ELECT 22uF 20% 50V C422 1-164-159-11 CERAMIC 0.1uF 50V C423 1-164-159-11 CERAMIC 0.1uF 50V C439 1-126-514-11 ELECT 22uF 20% 16V C440 1-136-162-00 FILM 0.056uF 5% 50V C449 1-162-302-11 CERAMIC 0.0022uF 30% 16V C452 1-162-306-11 CERAMIC 0.01uF 20% 16V C471 1-164-159-11 CERAMIC 0.1uF 50V C472 1-126-795-11 ELECT 10uF 20% 50V C473 1-126-059-11 ELECT 10uF 20% 50V C474 1-126-059-11 ELECT 10uF 20% 50V C475 1-126-059-11 ELECT 10uF 20% 50V C476 1-164-159-11 CERAMIC 0.1uF 50V C477 1-126-059-11 ELECT 10uF 20% 50V C478 1-164-159-11 CERAMIC 0.1uF 50V C479 1-162-294-31 CERAMIC 0.001uF 10% 50V C481 1-162-290-31 CERAMIC 470PF 10% 50V C482 1-164-159-11 CERAMIC 0.1uF 50V C483 1-164-159-11 CERAMIC 0.1uF 50V C509 1-126-233-11 ELECT 22uF 20% 50V C510 1-126-233-11 ELECT 22uF 20% 50V C511 1-162-207-31 CERAMIC 22PF 5% 50V C512 1-136-177-00 FILM 1uF 5% 50V C513 1-136-177-00 FILM 1uF 5% 50V C514 1-126-961-11 ELECT 2.2uF 20% 50V C515 1-137-364-11 FILM 0.001uF 5% 50V C516 1-136-165-00 FILM 0.1uF 5% 50V C517 1-126-233-11 ELECT 22uF 20% 50V C521 1-126-233-11 ELECT 22uF 20% 50V C522 1-162-306-11 CERAMIC 0.01uF 20% 16V C523 1-162-306-11 CERAMIC 0.01uF 20% 16V C539 1-126-514-11 ELECT 22uF 20% 16V C540 1-136-162-00 FILM 0.056uF 5% 50V C549 1-162-302-11 CERAMIC 0.0022uF 30% 16V C920 1-164-159-11 CERAMIC 0.1uF 50V C921 1-164-159-11 CERAMIC 0.1uF 50V C922 1-126-052-11 ELECT 100uF 20% 16V C923 1-126-052-11 ELECT 100uF 20% 16V C924 1-126-023-11 ELECT 100uF 20% 25V C925 1-126-023-11 ELECT 100uF 20% 25V C926 1-126-052-11 ELECT 100uF 20% 16V < CONNECTOR > CN420 1-770-383-11 CONNECTOR, BOARD TO BOARD 14P * CN421 1-568-864-11 SOCKET, CONNECTOR 21P CN422 1-770-381-11 CONNECTOR, BOARD TO BOARD 10P CN423 1-564-707-11 PIN, CONNECTOR (SMALL TYPE) 5P < DIODE > D921 8-719-001-21 DIODE UZL-9H1 D922 8-719-001-21 DIODE UZL-9H1 < IC > IC404 8-759-711-35 IC NJM4580D IC410 8-759-275-23 IC BU2092 IC422 8-759-195-20 IC SC027MG066BCP IC423 8-759-195-16 IC SC027MG052BCP IC424 8-759-070-78 IC TC9211P IC430 8-759-711-35 IC NJM4580D IC530 8-759-711-35 IC NJM4580D < TRANSISTOR > Q420 8-729-422-57 TRANSISTOR UN4111 Q421 8-729-422-57 TRANSISTOR UN4111 Q422 8-729-900-80 TRANSISTOR DTC114ES Q424 8-729-141-30 TRANSISTOR 2SC3623A-LK Q524 8-729-141-30 TRANSISTOR 2SC3623A-LK Q921 8-729-140-96 TRANSISTOR 2SD774-34 Q924 8-729-140-97 TRANSISTOR 2SB734-34 < RESISTOR > R421 1-249-437-11 CARBON 47K 5% 1/4W R422 1-249-441-11 CARBON 100K 5% 1/4W R423 1-249-417-11 CARBON 1K 5% 1/4W F R424 1-249-429-11 CARBON 10K 5% 1/4W R425 1-247-887-00 CARBON 220K 5% 1/4W R426 1-249-442-11 CARBON 510 5% 1/4W R427 1-247-858-11 CARBON 13K 5% 1/4W R428 1-249-421-11 CARBON 2.2K 5% 1/4W F R429 1-249-429-11 CARBON 10K 5% 1/4W R442 1-249-428-11 CARBON 8.2K 5% 1/4W F R443 1-247-887-00 CARBON 220K 5% 1/4W R444 1-249-437-11 CARBON 47K 5% 1/4W R445 1-249-431-11 CARBON 15K 5% 1/4W R446 1-249-435-11 CARBON 33K 5% 1/4W R448 1-249-435-11 CARBON 33K 5% 1/4W R449 1-249-421-11 CARBON 2.2K 5% 1/4W F R450 1-247-807-31 CARBON 100 5% 1/4W R451 1-249-426-11 CARBON 5.6K 5% 1/4W R460 1-247-887-00 CARBON 220K 5% 1/4W R470 1-247-807-31 CARBON 100 5% 1/4W R472 1-247-807-31 CARBON 100 5% 1/4W R473 1-247-807-31 CARBON 100 5% 1/4W R474 1-247-807-31 CARBON 100 5% 1/4W R475 1-247-807-31 CARBON 100 5% 1/4W R476 1-247-807-31 CARBON 100 5% 1/4W R478 1-249-417-11 CARBON 1K 5% 1/4W F R479 1-249-425-11 CARBON 4.7K 5% 1/4W F R481 1-247-807-31 CARBON 100 5% 1/4W R482 1-247-807-31 CARBON 100 5% 1/4W R483 1-247-807-31 CARBON 100 5% 1/4W PRE www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks — 58 — R484 1-247-807-31 CARBON 100 5% 1/4W R485 1-247-807-31 CARBON 100 5% 1/4W R486 1-249-437-11 CARBON 47K 5% 1/4W R487 1-249-437-11 CARBON 47K 5% 1/4W R488 1-249-432-11 CARBON 18K 5% 1/4W R489 1-249-437-11 CARBON 47K 5% 1/4W R490 1-249-437-11 CARBON 47K 5% 1/4W R491 1-249-413-11 CARBON 470 5% 1/4W F R493 1-249-413-11 CARBON 470 5% 1/4W F R494 1-249-413-11 CARBON 470 5% 1/4W F R521 1-249-437-11 CARBON 47K 5% 1/4W R522 1-249-441-11 CARBON 100K 5% 1/4W R523 1-249-417-11 CARBON 1K 5% 1/4W F R524 1-249-429-11 CARBON 10K 5% 1/4W R525 1-247-887-00 CARBON 220K 5% 1/4W R526 1-249-442-11 CARBON 510 5% 1/4W R527 1-247-858-11 CARBON 13K 5% 1/4W R528 1-249-421-11 CARBON 2.2K 5% 1/4W F R529 1-249-429-11 CARBON 10K 5% 1/4W R542 1-249-428-11 CARBON 8.2K 5% 1/4W F R543 1-247-887-00 CARBON 220K 5% 1/4W R544 1-249-437-11 CARBON 47K 5% 1/4W R545 1-249-431-11 CARBON 15K 5% 1/4W R546 1-249-435-11 CARBON 33K 5% 1/4W R548 1-249-435-11 CARBON 33K 5% 1/4W R549 1-249-421-11 CARBON 2.2K 5% 1/4W F R551 1-249-426-11 CARBON 5.6K 5% 1/4W R560 1-247-887-00 CARBON 220K 5% 1/4W R921 1-247-843-11 CARBON 3.3K 5% 1/4W R925 1-247-843-11 CARBON 3.3K 5% 1/4W ************************************************************ * A-4403-559-A RDS BOARD, COMPLETE (AEP,G,UK) ******************** < CAPACITOR > C601 1-162-291-31 CERAMIC 560PF 10% 50V C602 1-162-306-11 CERAMIC 0.01uF 20% 16V C603 1-162-288-31 CERAMIC 330PF 10% 50V C604 1-126-961-11 ELECT 2.2uF 20% 50V C605 1-126-964-11 ELECT 10uF 20% 50V C606 1-162-291-31 CERAMIC 560PF 10% 50V C607 1-126-964-11 ELECT 10uF 20% 50V C608 1-164-159-11 CERAMIC 0.1uF 50V C609 1-126-967-11 ELECT 47uF 20% 16V C610 1-102-518-11 CERAMIC 33PF 5% 50V C611 1-102-518-11 CERAMIC 33PF 5% 50V C612 1-162-306-11 CERAMIC 0.01uF 20% 16V < CONNECTOR > CN601 1-779-939-11 CONNECTOR, BOARD TO BOARD 7P < DIODE > D601 8-719-911-19 DIODE 1SS119 < IC > IC601 8-759-450-86 IC BU1922 IC602 8-759-634-51 IC M5218AP < COIL > L601 1-410-977-11 INDUCTOR 100uH < RESISTOR > R601 1-249-401-11 CARBON 47 5% 1/4W F R602 1-249-441-11 CARBON 100K 5% 1/4W R603 1-249-441-11 CARBON 100K 5% 1/4W R604 1-249-426-11 CARBON 5.6K 5% 1/4W R605 1-249-429-11 CARBON 10K 5% 1/4W R606 1-249-405-11 CARBON 100 5% 1/4W F R607 1-249-417-11 CARBON 1K 5% 1/4W F < VIBRATOR > X601 1-579-900-21 VIBRATOR, CRYSTAL 4.332MHz ************************************************************ * 1-667-822-11 RELAY BOARD ************ < CAPACITOR > C820 1-126-794-11 ELECT 4.7uF 20% 50V C821 1-126-177-11 ELECT 100uF 20% 10V C822 1-164-159-11 CERAMIC 0.1uF 50V C823 1-164-159-11 CERAMIC 0.1uF 50V C824 1-164-159-11 CERAMIC 0.1uF 50V < CONNECTOR > * CN812 1-569-502-11 PIN, CONNECTOR 7P * CN813 1-691-174-11 CONNECTOR (BOARD TO BOARD) 4P CN814 1-564-506-11 PLUG, CONNECTOR 3P < DIODE > D820 8-719-933-50 DIODE HZS7C2L D821 8-719-933-39 DIODE HZS6C1L D822 8-719-911-19 DIODE 1SS119 D823 8-719-911-19 DIODE 1SS119 < TRANSISTOR > Q820 8-729-119-76 TRANSISTOR 2SA1175-HFE Q821 8-729-620-05 TRANSISTOR 2SC2603-EF Q822 8-729-620-05 TRANSISTOR 2SC2603-EF Q823 8-729-620-05 TRANSISTOR 2SC2603-EF Q824 8-729-140-96 TRANSISTOR 2SD774-34 < RESISTOR > R820 1-249-417-11 CARBON 1K 5% 1/4W F R821 1-249-441-11 CARBON 100K 5% 1/4W R822 1-249-429-11 CARBON 10K 5% 1/4W R823 1-249-441-11 CARBON 100K 5% 1/4W R824 1-249-413-11 CARBON 470 5% 1/4W F !R825 1-212-966-00 FUSIBLE 22 5% 1/2W F R826 1-249-441-11 CARBON 100K 5% 1/4W R827 1-249-441-11 CARBON 100K 5% 1/4W R828 1-249-429-11 CARBON 10K 5% 1/4W ************************************************************ PRE RDS RELAY The components identified by mark ! or dotted line with mark ! are critical for safety. Replace only with part number specified. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks — 59 — * 1-653-378-51 SENSOR BOARD ************* < DIODE > D801 8-719-045-75 DIODE CL-200IR-X-TU D803 8-719-045-75 DIODE CL-200IR-X-TU D804 8-719-045-75 DIODE CL-200IR-X-TU < RESISTOR > R801 1-216-049-91 METAL GLAZE 1K 5% 1/10W R803 1-216-049-91 METAL GLAZE 1K 5% 1/10W R804 1-216-049-91 METAL GLAZE 1K 5% 1/10W < SWITCH > S802 1-692-441-11 SWITCH, MICROPHONE ************************************************************ * 1-667-386-11 SP TM BOARD ************ < CAPACITOR > C806 1-164-159-11 CERAMIC 0.1uF 50V (AEP,G,UK) C856 1-164-159-11 CERAMIC 0.1uF 50V (AEP,G,UK) < CONNECTOR > CN803 1-691-161-11 PIN, CONNECTOR 4P < COIL > L801 1-420-872-00 COIL, AIR-CORE (AEP,G,UK) L851 1-420-872-00 COIL, AIR-CORE (AEP,G,UK) < RESISTOR > R805 1-260-076-11 CARBON 10 5% 1/2W (AEP,G,UK) R806 1-249-393-11 CARBON 10 5% 1/4W F (AEP,G,UK) R855 1-260-076-11 CARBON 10 5% 1/2W (AEP,G,UK) R856 1-249-393-11 CARBON 10 5% 1/4W F (AEP,G,UK) < TERMINAL > TM801 1-537-238-31 TERMINAL BOARD (SPEAKER IMPEDANCE USE 4-16 (L+,L-,R+,R-)) ************************************************************ * 1-667-385-11 SWITCH BOARD ************* < CONNECTOR > CN751 1-766-928-11 CONNECTOR, BOARD TO BOARD 8P < DIODE > D751 8-719-056-12 DIODE SML79420C-TP4 (PLAY/PAUSE) < RESISTOR > R750 1-249-427-11 CARBON 6.8K 5% 1/4W F R751 1-249-429-11 CARBON 10K 5% 1/4W R752 1-247-858-11 CARBON 13K 5% 1/4W R753 1-249-433-11 CARBON 22K 5% 1/4W R762 1-249-425-11 CARBON 4.7K 5% 1/4W F R763 1-249-427-11 CARBON 6.8K 5% 1/4W F R764 1-249-429-11 CARBON 10K 5% 1/4W R765 1-247-858-11 CARBON 13K 5% 1/4W < SWITCH > S751 1-762-875-21 SWITCH, KEYBOARD (DBFB) S752 1-762-875-21 SWITCH, KEYBOARD (VOL–) S753 1-762-875-21 SWITCH, KEYBOARD (VOL+) S754 1-762-875-21 SWITCH, KEYBOARD (FUNCTION) S762 1-762-875-21 SWITCH, KEYBOARD (BAND) S763 1-762-875-21 SWITCH, KEYBOARD (TUNE–/ 0 / =) S764 1-762-875-21 SWITCH, KEYBOARD (TUNE+/ ) / + ) S765 1-762-875-21 SWITCH, KEYBOARD (flPLAY/PAUSE) S766 1-762-875-21 SWITCH, KEYBOARD (p) ************************************************************ * 1-667-384-11 TRANS BOARD ************ 1-533-293-11 FUSE HOLDER < CONNECTOR > * CN902 1-573-047-11 PIN, CONNECTOR (PC BOARD) 2P CN905 1-691-770-11 PLUG (MICRO CONNECTOR) 8P < FUSE > !F901 1-532-388-51 FUSE TIME, LAG 2A/250V ************************************************************ * 1-667-382-11 VOLSEL BOARD (MY, SP, HK, JE) ************* 1-533-293-11 FUSE HOLDER < CONNECTOR > * CN920 1-564-507-11 PLUG, CONNECTOR 4P < FUSE > !F902 1-532-505-51 FUSE TIME, LAG 5A/250V !F903 1-532-505-51 FUSE TIME, LAG 5A/250V < SWITCH > !S901 1-554-752-11 SELECTOR, POWER VOLTAGE (VOLTAGE SELECTOR) ************************************************************ SP TM SENSOR SWITCH TRANS VOLSEL The components identified by mark ! or dotted line with mark ! are critical for safety. Replace only with part number specified. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks — 60 — HCD-101 Sony Corporation Home A&V Products Company 97I1675-1 Printed in Japan © 1997.9 Published by General Engineering Dept. (Shibaura) 9-920-988-11 MISCELLANEOUS ************** 13 1-782-805-11 WIRE (FLAT TYPE) (5 CORE) 14 1-782-781-11 WIRE (FLAT TYPE) (27 CORE) 54 1-782-780-11 WIRE (FLAT TYPE) (21 CORE) 58 1-698-997-11 FAN, DC !65 1-776-060-11 CORD, POWER (EXCEPT UK) !65 1-776-061-21 CORD, POWER (UK) !72 1-569-008-11 ADAPTOR, CONVERSION 2P (SP,MY) !73 1-770-019-11 ADAPTOR, CONVERSION PLUG 3P (HK) !152 8-848-283-11 OPTICAL PICK-UP KSS-313A M101 X-3367-484-2 MOTOR (SP) ASSY (SPINDLE) M102 A-3252-585-A MOTOR (SL) ASSY (SLED) M103 A-3252-580-A MOTOR (L) ASSY (LOADING) !T901 1-431-559-11 TRANSFORMER, POWER (AEP,G,UK) !T901 1-431-560-11 TRANSFORMER, POWER (SP,MY,HK,JE) ************************************************************ ************** HARDWARE LIST ************** #1 7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S #2 7-685-871-09 SCREW +BVTT 3X6 (S) #3 7-685-862-09 SCREW +BVTT 2.6X6 (S) #4 7-685-647-79 SCREW +BVTP 3X10 TYPE2 N-S #5 7-685-871-01 SCREW +BVTT 3X6 (S) #6 7-621-772-60 SCREW +B 2X12 #7 7-627-852-17 +P 1.7X4 #8 7-627-553-37 SCREW , PRECISION +P2X3 #9 7-627-553-67 SCREW , PRECISION +P2X5 #10 7-685-851-01 SCREW +BVTT 2X4 (S) The components identified by mark ! or dotted line with mark ! are critical for safety. Replace only with part number specified. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com
