MICROFILM SERVICE MANUAL STEREO CASSETTE DECK AEP Model UK Model Australian Model Model Name Using Similar Mechanism TC-KE400S Tape Transport Mechanism Type TCM-190VB12CSS SPECIFICATIONS Dolby noise reduction and HX Pro headroom ex- tension manufactured under license from Dolby Laboratories Licensing Corporation. HX Pro origi- nated by Bang & Olufsen. “DOLBY”, the double-D symbol a, and “HX PRO” are trademarks of Dolby Laboratories Licensing Cor- poration. – Continued on next page – www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 2 – Flexible Circuit Board Repairing • Keep the temperature of the soldering iron around 270 ˚C dur- ing repairing. • Do not touch the soldering iron on the same conductor of the circuit board (within 3 times). • Be careful not to apply force on the conductor when soldering or unsoldering. Notes on chip component replacement • Never reuse a disconnected chip component. • Notice that the minus side of a tantalum capacitor may be dam- aged by heat. SAFETY-RELATED COMPONENT WARNING!! COMPONENTS IDENTIFIED BY MARK ! OR DOTTED LINE WITH MARK ! ON THE SCHEMATIC DIAGRAMS AND IN THE PARTS LIST ARE CRITICAL TO SAFE OPERATION. REPLACE THESE COMPONENTS WITH SONY PARTS WHOSE PART NUMBERS APPEAR AS SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUB- LISHED BY SONY. MODEL IDENTIFICATION – BACK PANEL – 3-020-983- AEP Model : 0 π� UK Model : 1 π Australian Model : 2 π www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 3 – TABLE OF CONTENTS 1. GENERAL ................................................................... 4 2. DISASSEMBLY ......................................................... 5 3. MECHANICAL ADJUSTMENTS ....................... 9 4. ELECTRICAL ADJUSTMENTS......................... 10 5. DIAGRAMS 5-1. Note for Printed Wiring Boards and Schematic Diagrams ....................................................... 14 5-2. Printed Wiring Boards – MD Section –......................... 15 5-3. Schematic Diagram – MD Section – .............................. 17 5-4. Printed Wiring Board – MAIN Section – ...................... 19 5-5. Schematic Diagram – MAIN Section – (1/3) ................. 21 5-6. Schematic Diagram – MAIN Section – (2/3) ................. 23 5-7. Schematic Diagram – MAIN Section – (3/3) ................. 25 5-8. Printed Wiring Board – DOLBY-S Section –................ 29 5-9. Schematic Diagram – DOLBY-S Section – .................. 29 5-10. Printed Wiring Boards – PANEL Section – .................. 31 5-11. Schematic Diagram – PANEL Section – ........................ 33 5-12. IC Pin Function Description ........................................... 35 6. EXPLODED VIEWS ................................................ 37 7. ELECTRICAL PARTS LIST ............................... 42 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 4 – SECTION 1 GENERAL LOCATION OF CONTROLS 1 I/O (Power) button 2 Remote control sensor 3 PHONES jack 4 Display panel 5 Tape operation buttons AMS* 0 button · button AMS* ) button p button P PAUSE button R REC MUTING button r REC button 6 Tape counter 7 Counter buttons RESET button MEMORY button 8 Cassette holder 9 § EJECT button !º AUTO CAL button !¡ DOLBY NR switch !™ BALANCE control !£ REC LEVEL control * AMS is an abbreviation for Automatic Music Sensor. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 5 – FRONT PANEL SECTION MD ASS’Y SECTION Note: Follow the disassembly procedure in the numerical order given. SECTION 2 DISASSEMBLY CASE Unscrew the four case attachment seven tapping screws and remove the case. 1 flat cable (CN801) 3 screw (BVTP3 × 8) 5 four screws (BVTP3 × 8) 7 two connectors (CNP31, 33) 5 screw (BVTP3 × 8) 6 claw 6 claw 1 flat cable (CN504) 4 two earth lugs 2 connector (CN704) 1 flat cable (CN81) 2 connector (CN506) 8 front panel section 4 two screws (BVTT2.6 × 8) 6 Remove the MD ass’y section to direction of arrow A . 5 two screws (BVTP2.6 × 8) 2 two claws 1 push the eject button. 2 two claws 3 cassette lid ass’y A www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 6 – MAIN BOARD CASSETTE HOLDER (R) ASS’Y 4 two screws (BVTP3 × 8) 2 screw (BV/ring) 5 MAIN board 1 connector (CN701) 4 screw (BV/ring) 3 bracket (TR) 2 boss 3 shaft 1 torsion spring 4 cassette holder (R) ass’y www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 7 – FITTING BASE BLOCK HEAD 2 two screws (PTPWH2 × 23) 2 screw (PTPWH2 × 23) Note: When installing, pull the FR belt and put around the claws as shown below. 1 connector (CNP32) 3 fitting base block Note: When installing, pull the capstan belt and put around the claws as shown below. 2 screw (B2 × 10) 1 connector (CNP32) 4 azimuth screw 5 record/playback head 6 compression spring 3 erase head www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 8 – MOTOR 5 two screws (B2.6 × 3) 7 two screws (P2.6 × 2.8) 2 flexible board (CNP72) 1 connector (CNP71) 3 claw 3 claw 3 two claws 6 capstan motor !º ground plate 4 audio board 8 reel motor 9 FR belt www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 9 – SECTION 3 MECHANICAL ADJUSTMENTS PRECAUTION 1. Clean the following parts with a denatured alcohol-moistened swab: record/playback/erase head pinch roller rubber belts capstan idler 2. Demagnetize the record/playback head with a head demagne- tizer. (Head demagnetizer do not approach for the erase head.) 3. Do not use a magnetized screwdriver for the adjustment. 4. After the adjustments, apply suitable locking compound to the parts adjusted. 5. The adjustments should be performed with the rated power supply voltage unless otherwise noted. • Torque Measurement Mode Torque Meter Meter Reading Forward CQ-102C 30 to 60 g•cm (0.42 to 0.83 oz•inch) Forward back CQ-102C 2 to 7 g•cm tension (0.03 to 0.09 oz•inch) FF/REW CQ-201B 70 to 110 g•cm (0.98 to 1.52 oz•inch) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 10 – SECTION 4 ELECTRICAL ADJUSTMENTS Note: The adjustment should be performed in the order given in the ser- vice manual. As a rule, adjustments about playback should be per- formed before those about recording. The adjustments should be performed before for both L-CH and R- CH. • Switches and controls should be set as follows unless otherwise specified. DOLBY NR, MPX FILTER switch: OFF • Standard Record: Deliver the standard input signal level to the input jack and set the REC LEVEL control to obtain the standard output signal level. – Record Mode – 0 dB = 0.775 V Standard Input Level input terminal LINE IN source impedance 10 kΩ input signal level 0.5 V (–3.8 dB) Standard Output Level output terminal LINE OUT load impedance 47 kΩ output signal level 0.5 V (–3.8 dB) Test Tape Type Signal Used for P-4-A100 10 kHz, –10 dB Azimuth Adjustment P-4-L300 315 Hz, 0 dB Playback Level Adjustment WS-48B 3 kHz, 0 dB Tape Speed Adjustment Test Mode 1. Insert a short-circuit plug into TP801 (2P) and turn ON the power switch. (Earth pin &ª of IC801 and turn ON the power switch.) At first, all the fluorescent tubes light up, then the system re- turns to normal display. (However, “00 00” is not displayed on the counter.) 2. To release the test mode, remove the short plug and turn off the power switch. 3. Remove the short plug after completion of adjustment. + – set 47 k Ω LINE OUT LINE IN 600 Ω 10 k Ω attenuator AF OSC level meter Record/Playback Head Azimuth Adjustment Procedure: 1. Mode : FWD playback 2. Turn the adjustment screw for the maximum output levels. If these levels do not match, turn the adjustment screw until both of output levels match together within 1 dB. 3. Phase Check Mode : playback 4. After the adjustment, lock the screw with locking compound. Adjustment Location: Record/Playback head + – set 47 k Ω LINE OUT level meter Test tape P-4-A100 (10 kHz, –10 dB) Screw position L-CH peak within 1dB output level L-CH peak R-CH peak within 1dB angle R-CH peak + – V H + – Screen pattern Good Wrong in phase 45 ° 90 ° 135 ° 180 ° LINE OUT set R-CH L-CH 47 k Ω 47 k Ω oscilloscope test tape P-4-A100 (10 kHz, –10 dB) Adjustment screw www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 11 – Tape Speed Adjustment Procedure: Mode: playback 1. Set to FWD playback mode. 2. Adjust RV71 so that the frequency counter reading becomes 3,000 ± 90 Hz. 3. If, the frequency counter reading does not become 3,000 ± 90Hz. Turn RV72 and back to 1st. step again. Note: Turn RV72 to clockwise – Tape speed becomes fast. Turn RV72 to counter clockwise – Tape speed becomes slow. 4. Frequency difference between the beginning and the end of the tape should be within 1%. Adjustment Location: AUDIO board (See page 12.) Sample value of Wow and Flutter: 0.3% or less W.RMS (JIS) (WS-48B) Playback Level Adjustment Procedure: Mode: playback Adjust RV11 (L-CH) and RV21 (R-CH) so that the reading on level meter meets the adjustment limits below. Adjustment Limits: LINE OUT level: –7.7±0.5 dB (0.301 to 0.338 V) Level difference between channels: within 0.5 dB Check that the LINE OUT level does not change even if Playback and Stop operation is repeated several times. Adjustment Location: AUDIO board (See page 12.) + – set LINE OUT frequency counter test tape WS-48B (3 kHz, 0 dB) 47 k Ω + – set LINE OUT 47 k Ω test tape P-4-L300 (315 Hz, 0 dB) level meter Bias Consumption Current Adjustment Procedure: 1. Set RV81 (L-CH) and RV91 (R-CH) to mechanical center and turn the set recording mode. 2. Connect digital voltmeter as shown by the following table. 3. Adjust the following transformers for the minimum readings on the digital voltmeter. Measurement Point Adjustment Part Value L-CH 1 and 2, TP321 T81 minimum R-CH 3 and 2, TP321 T91 Adjustment Location: AUDIO board (See page 12.) Record Bias Adjustment Setting: REC LEVEL control: Standard Record (See page 10.) Procedure: 1. Mode: record 2. Mode: playback 3. Adjust RV81(L-CH) and RV91 (R-CH) so that 10 kHz play- back output is 0±0.5 dB relative to the 315 Hz output. Adjustment Location: AUDIO board (See page 12.) – + set LINE IN (no signal) B+ (+7.5 V) TP81 3 2 1 R-CH L-CH digital voltmeter CS-413 blank tape set AF OSC Attenuator LINE IN 315 Hz 10 kHz 50 mV (–23.8 dB) 600 Ω 10 k Ω CS-123 blank tape + – set LINE OUT 47 k Ω recorded portion level meter www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 12 – Record Level Adjustment Setting: REC LEVEL control: Standard Record (See page 10.) Procedure: 1. Mode: record 2. Mode: playback 3. Adjust RV111 (L-CH) and RV211 (R-CH) so that the reading on level meter meets the adjustment limits below. Adjustment Limits: –3.8 ± 0.5 dB (0.47 to 0.53 V) Adjustment Location: MAIN board [AUDIO BOARD] –SIDE A – set AF OSC Attenuator 600 Ω 10 k Ω CS-123 blank tape LINE IN 315 Hz, 0.5 V (–3.8 dB) + – set LINE OUT 47 k Ω recorded portion level meter Adjustment Location: [MAIN BOARD] –COMPONENT SIDE – DOLBY-S BOARD RV211 RV111 J501 CN831 CN833 TP801 RV72 RV71 RV21 RV11 T81 T91 RV81 IC31 TP81 RV91 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 13 – – 14 – SECTION 5 DIAGRAMS • Circuit Boards Location TRANSFORMER board AC POWER SW board HP board PANEL board LEAF SW board REC VOL board DOLBY-S boards MAIN board AUDIO board 5-1. NOTE FOR PRINTED WIRING BOARDS AND SCHEMATIC DIAGRAMS (In addition to this, the necessary note is each block.) Note on Schematic Diagram: • All capacitors are in µF unless otherwise noted. pF: µµF 50 WV or less are not indicated except for electrolytics and tantalums. • All resistors are in Ω and 1/4 W or less unless otherwise specified. • ¢ : internal component. • 2 : nonflammable resistor. • C : panel designation. • U : B+ Line. • V : B– Line. • Voltages and waveforms are dc with respect to ground under no-signal conditions. no mark : PB ( ) : REC ∗ : Impossible to measure • Voltages are taken with a VOM (Input impedance 10 MΩ). Voltage variations may be noted due to normal produc- tion tolerances. • Waveforms are taken with a oscilloscope. Voltage variations may be noted due to normal produc- tion tolerances. • Circled numbers refer to waveforms. • Signal path. E : PB a : REC Note: The components identified by mark ! or dotted line with mark ! are critical for safety. Replace only with part number specified. Note on Printed Wiring Boards: • X : parts extracted from the component side. • Y : parts extracted from the conductor side. • r : Through hole. • b : Pattern from the side which enables seeing. (The other layers' patterns are not indicated.) Caution: Pattern face side: Parts on the pattern face side seen from (Side B) the pattern face are indicated. Parts face side: Parts on the parts face side seen from (Side A) the parts face are indicated. • Indication of transistor. B These are omitted. C E Q B These are omitted. C E Q w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 15 – – 16 – TC-KB820S 5-2. PRINTED WIRING BOARDS – MD Section – • See page 13 for Circuit Boards Location. • Semiconductor Location Ref. No. Location D31 C-1 IC31 C-2 IC81 B-3 •IC81 G-4 Q51 B-2 Q52 B-2 Q53 B-2 Q71 C-4 (Note) •:LEAF SW BOARD (Page 20) (Page 19) (Page 19) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com TC-KB820S – 18 – – 17 – 5-3. SCHEMATIC DIAGRAM – MD Section – • See page 27 for Waveforms. (Page 21) (Page 21) (Page 23) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 19 – – 20 – TC-KB820S 5-4. PRINTED WIRING BOARD – MAIN Section – • See page 13 for Circuit Boards Location. • Semiconductor Location Ref. No. Location D131 C-5 D132 C-5 D231 C-5 D232 C-5 D511 B-7 D512 B-7 D513 E-7 D551 B-5 D701 G-2 D702 G-2 D703 G-2 D704 G-2 D705 F-2 D706 F-2 D707 F-2 D708 G-3 D709 G-5 D710 F-3 D711 F-4 D712 F-3 D713 E-1 D714 E-3 D715 F-4 D801 D-2 D802 D-2 IC501 C-9 IC502 F-9 IC503 D-6 IC504 C-5 IC505 D-5 IC506 A-9 IC507 C-7 IC508 B-4 IC509 C-4 IC510 B-6 IC511 F-10 IC512 D-9 IC601 A-3 IC701 G-4 IC801 B-2 IC802 D-2 Q101 A-8 Q102 B-8 Q103 E-8 Q121 F-6 Q122 D-7 Q201 A-8 Q202 B-10 Q203 E-9 Q221 F-6 Q222 D-7 Q503 E-8 Q511 B-6 Q512 B-7 Q521 F-7 Q531 B-5 Q532 B-5 Q551 A-5 Q572 F-7 Q573 C-7 Q601 B-3 Q701 G-6 Q702 G-5 Q704 G-4 Q705 F-3 Q707 F-3 Q708 F-2 Q805 D-2 (Page 32) (Page 31) (Page 15) (Page 32) (Page 31) (Page 29) (Page 29) (Page 15) (Page 15) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com TC-KB820S – 22 – – 21 – 5-5. SCHEMATIC DIAGRAM – MAIN Section – (1/3) (Page 30) (Page 34) (Page 18) (Page 18) (Page 30) (Page 23) (Page 23) The components identified by mark ! or dotted line with mark ! are critical for safety. Replace only with part number specified. w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 23 – – 24 – TC-KB820S 5-6. SCHEMATIC DIAGRAM – MAIN Section – (2/3) • See page 27 for Waveforms. (Page 22) (Page 22) (Page 18) (Page 25) (Page 25) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com TC-KB820S – 26 – – 25 – 5-7. SCHEMATIC DIAGRAM – MAIN Section – (3/3) • See page 28 for IC Block Diagrams. The components identified by mark ! or dotted line with mark ! are critical for safety. Replace only with part number specified. (Page 33) (Page 33) (Page 34) (Page 24) (Page 24) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 27 – – 28 – • Waveforms – AUDIO BOARD – 1 T51 1 2 Q51 C, Q52 C 3 T81 4 4 T91 4 6 IC81 !¡, !™ – MAIN BOARD (2/3) – 1 IC801 #¡ 5 IC81 7, 8 118 Vp-p 9.3 µs 26.4 Vp-p 9.3 µs 63.2 Vp-p 9.3 µs 64.8 Vp-p 9.3 µs 6.4 Vp-p 9.3 µs 4.3 Vp-p 6 MHz 6.2 Vp-p 9.3 µs • IC Block Diagrams 2 1 RECOUT SCINL ANTSAT MC3IN MC4IN HLSOUT MCBO VCC IREF SCBOL TCS2L TCS1L FBOL TCF1L TCF2L 4 LFIN 3 TCL2 ZL2 5 9 8 7 6 TCL1 SCINH TCS1H ZL1 HLSMP MCTC 10 11 12 13 VCT 14 VEE 15 24 25 26 27 28 29 30 20 21 22 23 19 17 18 16 TCS2H TCF2H FBOH TCF1H ANTSAT FLVCR SLVCR FHVCR LFICG LFVCR LFDET SHVCR SLDET SLICG SHICG SHDET FLDET FHDET FLICG FHICG V TO I CONV H V TO I CONV H VREF & IREF MC4 MC3DS MC3DT MC2 MC1 MC4 MC3 MC1 MC IC1 CXA1917AM-T6 (DOLBY-S BOARD) IC502 CXA1579P (MAIN BOARD) 2 1 MUTE R.CAL G.CAL IN I.REF BOOST VCC OUT 4 3 5 9 8 7 6 VEE IN 10 11 12 13 GND 14 BOOST 15 16 70US METAL OUT SPEED CONTROL REC EQ AMP REC EQ AMP BIAS + – VGS VEE VCC w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 30 – – 29 – TC-KB820S 5-9. SCHEMATIC DIAGRAM – DOLBY-S Section – • See page 28 for IC Block Diagrams. 5-8. PRINTED WIRING BOARD – DOLBY-S Section – • See page 13 for Circuit Boards Location. (Page 21) (Page 20) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 31 – – 32 – TC-KB820S 5-10. PRINTED WIRING BOARDS – PANEL Section – • See page 13 for Circuit Boards Location. (Page 19) (Page 19) (Page 32) (Page 32) (Page 19) (Page 20) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com TC-KB820S – 34 – – 33 – 5-11. SCHEMATIC DIAGRAM – PANEL Section – The components identified by mark ! or dotted line with mark ! are critical for safety. Replace only with part number specified. (Page 21) (Page 26) (Page 26) (Page 26) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 5-12. IC PIN FUNCTION DESCRIPTION • MAIN BOARD IC801 CXP82612-022Q (SYSTEM CONTROLLER) – 35 – – 36 – Pin No. Pin Name I/O Function 1 STOP SW I Mechanism stop detect switch (S81) input terminal 2 SIRCS IN I Sircs signal input from the remote control receiver (IC901) 3 VERSION2 I Setting terminal for the version (fixed at “L”) 4 to 6 NC O Not used (open) 7 MPX ON/OFF O Multiplex filter on/off control signal output terminal “H”: multiplex filter on 8 CAL ON/OFF O Calibration on/off control signal output terminal “H”: calibration on 9 REC CAL 0 O 10 REC CAL 1 O 11 GP CAL 0 O 12 GP CAL 1 O 13 LINE MUTE O Line muting on/off control signal output terminal “L”: line muting on 14 AMS IN I Auto music sensor signal input terminal “H”: AMS detect 15 NC O Not used (open) 16 REC MUTE O Record muting on/off control signal output to the CXA1579P (IC502) “H”: record muting on 17 REEL – O 18 REEL + O 19 BIAS O Recording bias on/off control signal output terminal “H”: bias on 20 RELAY O Relay drive signal output for the record/playback selection relay “L”: playback mode, “H”: recording mode 21 CAL KEY I AUTO CAL switch (S921) input terminal 22 METER L I Signal input for the level meter drive (L-ch) 23 KEY X I Key input terminal (A/D input) (S901 to S904) p, AMS 0, AMS ), r REC keys input 24 KEY Y I Key input terminal (A/D input) (S905 to S909) R REC MUTING, ·, P PAUSE, MEMORY, RESET keys input 25 METER R I Signal input for the level meter drive (R-ch) 26 DOLBY AD I DOLBY NR switch (S922) input terminal (A/D input) 27 HALF I Half detect switch (S86) input terminal 28 METAL CHROM I Metal detect switch (S83) and CrO2 detect switch (S82) input terminal “H”: metal or CrO2 29 S.REEL I Supply reel rotation pulse input from the rotation detect sensor (IC81) 30 RESET I System reset signal input from the reset signal generator (IC802) “L”: reset “L” is input for several 100 msec after power on, then it changes to “H” 31 XO O System clock output terminal (6 MHz) 32 XI I System clock input terminal (6 MHz) 33 VSS — Ground terminal 34 BIAS CAL 0 O 35 BIAS CAL 1 O 36 BIAS CAL 2 O 37 BIAS CAL 3 O 38 CAP.M ON/OFF O Capstan motor (M902) on/off control signal output terminal “H”: motor on 39 OSC H/L O Calibration tone frequency high/low control signal output terminal “L”: frequency high 40 OSC ON/OFF O Calibration tone on/off control signal output terminal “H”: off, “L”: on 41 BC/S O Dolby B and C type or dolby S type selection signal output to the CXA1563S (IC501) “H”: dolby B and C type, “L”: dolby S type 42 DOLCON O Dolby B type or dolby C type selection signal output to the CXA1563S (IC501) “H”: dolby C type, “L”: dolby off (high impedance: dolby B type) Recording calibration up/down control signal output to the CXA1579P (IC502) “H”: up, “L”: down (high impedance: off) Equalizer calibration up/down control signal output to the CXA1579P (IC502) “H”: up, “L”: down (high impedance: off) Reel motor (M901) drive signal output terminal Equalizer bias calibration control signal output terminal Pin No. Pin Name I/O Function 43 REC/PB O Recording/playback control signal output to the CXA1563S (IC501) “L”: recording mode, “H”: playback mode 44, 45 NC O Not used (open) 46 to 61 S1 to S16 O Segment drive signal output to the fluorescent indicator tube (FL901) 62 S18 O Segment drive signal output to the fluorescent indicator tube (FL901) 63 to 65 NC O Not used (open) 66 to 70 G5 to G1 O Grid drive signal output to the fluorescent indicator tube (FL901) 71 V-DISP — Power supply terminal for the fluorescent indicator tube drive (–20V) 72 VDD — Power supply terminal (+5V) 73, 74 NC O Not used (open) 75 VDD — Power supply terminal (+5V) 76 POWER IN I AC in detect signal input terminal “H”: AC in 77 POWER OUT O Power on/off control signal output terminal “L”: power on Not used (open) 78 VDD — Power supply terminal (+5V) 79 TEST MODE I Setting terminal for the test mode “L”: test mode (Normally: fixed at “H”) 80 VERSION1 I Setting terminal for the version (fixed at “L”) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 37 – SECTION 6 EXPLODED VIEWS The components identified by mark ! or dotted line with mark ! are critical for safety. Replace only with part number specified. • Items marked “*” are not stocked since they are seldom required for routine service. Some delay should be anticipated when ordering these items. • The mechanical parts with no reference num- ber in the exploded views are not supplied. • Hardware (# mark) list and accessories and packing materials are given in the last of the electrical parts list. NOTE: • -XX and -X mean standardized parts, so they may have some difference from the original one. • Color Indication of Appearance Parts Example: KNOB, BALANCE (WHITE) . . . (RED) ↑ ↑ Parts Color Cabinet's Color Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark (1) CASE, CHASSIS SECTION rA: TRANSFORMER board 2 3 2 2 4 5 (including rA– rE) #1 #1 T901 rA #1 #1 #1 not supplied #2 #2 FRONT PANEL SECTION 11 11 6 2 1 9 1 not supplied not supplied not supplied not supplied UK AEP Australian 7 7 7 A A 11 10 1 X-4949-523-1 FOOT ASSY (F50180S) 2 3-710-901-11 SCREW, TAPPING * 3 3-021-377-01 CASE * 4 A-2007-481-A DOLBY-S BOARD, COMPLETE * 5 A-2007-779-A MAIN BOARD, COMPLETE 6 4-966-267-11 BUSHING (FBS001), CORD !7 1-575-651-21 CORD, POWER (AEP) !7 1-696-586-11 CORD, POWER (UK) !7 1-696-845-11 CORD, POWER (Australian) * 8 3-020-983-01 PANEL, BACK (AEP) * 8 3-020-983-11 PANEL, BACK (UK) * 8 3-020-983-22 PANEL, BACK (Australian) 9 3-703-249-21 SCREW, S TIGHT, +PTTWH (M3X8) 10 4-956-370-12 BAND, PLUG FIXED (UK, Australian) 11 3-704-515-21 SCREW (BV/RING) !T901 1-427-751-11 TRANSFORMER, POWER www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 38 – Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 51 3-020-978-01 KNOB (REC) 52 3-020-979-01 KNOB (BALANCE) 53 X-3374-953-1 LID ASSY, CASSETTE 54 4-942-568-41 EMBLEM (NO.5), SONY 55 3-020-971-01 PANEL, FRONT (AEP,UK) 55 3-020-971-21 PANEL, FRONT (Australian) 56 3-020-980-01 WINDOW (METER) 57 4-922-921-62 BUTTON (POWER) 58 4-951-620-01 SCREW (2.6X8), +BVTP 59 1-696-456-11 WIRE (FLAT TYPE) (31 CORE) 60 1-590-486-11 WIRE (FLAT TYPE) (7 CORE) 61 3-020-975-01 BUTTON (CONTROL) 62 3-020-977-01 BUTTON (AUTO CAL) 63 3-933-299-01 KNOB (DIA. 12) 64 X-3375-506-1 BASE (KB820S) ASSY, PANEL 65 3-937-169-01 SPRING, TENSION 66 3-020-976-01 BUTTON (EJECT) 67 3-354-981-11 SPRING (SUS), RING (2) FRONT PANEL SECTION rB: AC POWER SW board rC: HP board rD: PANEL board rE: REC VOL board 58 58 60 61 57 #4 #3 MD ASS’Y SECTION rC rD rE rB 59 58 58 62 64 63 65 58 66 51 52 67 53 54 55 56 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 39 – 101 X-3368-119-1 HOLDER (R) ASSY, CASSETTE 102 3-354-963-01 DAMPER 103 1-769-914-11 WIRE (FLAT TYPE) (9 CORE) 104 3-354-957-01 JOINT (LOCK LEVER) * 105 3-354-954-01 LEVER (LOCK LEVER R) 106 3-354-962-01 SPRING (EJ SAFTY SPRING R) 107 3-354-956-01 LEVER (EJ SAFTY LEVER R) 108 3-354-960-01 SPRING (LOADING R), TORSION Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark (13) MD ASS’Y SECTION 102 #5 TCM-190VB12CSS 103 104 105 106 108 101 107 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 40 – 151 3-907-362-01 SPRING, TORSION 152 A-2004-673-A DECK (ONE) ASSY, HEAD (including HRP901) 153 3-343-484-01 SPRING, COMPRESSION * 154 3-359-445-11 HOLDER (1 WAY HEAD) 155 X-3374-992-1 SLIDER (LIMITER) ASSY 156 3-363-868-01 SPRING (HEAD CHASSIS), TENSION 157 X-3367-629-1 FLYWHEEL (FWD) ASSY 158 3-359-467-01 BELT (1 WAY FLAT BELT) 159 3-359-436-11 BASE (THRUST RETAINER), FITTING 160 3-359-414-01 SCREW (+PTPWH 2X23) 161 1-638-983-11 MOTOR FLEXIBLE BOARD * 162 A-2007-780-A AUDIO BOARD, COMPLETE 163 3-359-466-01 BELT (FR), SQUARE Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark * 164 1-638-020-11 LEAF SW BOARD 165 3-359-430-01 SPRING (CASSETTE RETAINER), LEAF 166 3-575-321-00 RETAINER, THRUST, CAPSTAN 167 3-359-424-01 GEAR (REV GEAR) 168 X-3366-971-1 TABLE ASSY (B), REEL 169 3-362-308-01 CAP (REEL) 170 3-356-713-01 WASHER 171 X-3366-970-1 TABLE ASSY, REEL 172 X-3366-047-1 LEVER (PINCH F) ASSY HE901 1-543-673-11 HEAD, MAGNETIC (ERASE) M901 X-3363-501-2 MOTOR ASSY (REEL) M902 X-3374-302-1 MOTOR ASSY (CAPSTAN) 158 #7 M902 M901 not supplied not supplied #8 #6 not supplied not supplied 159 166 160 160 161 160 162 163 HE901 not supplied 157 164 165 167 168 169 169 170 171 153 151 156 155 152 154 172 (4) MECHANISM DECK SECTION-1 (TCM-190VB12CSS) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 41 – 201 3-359-469-01 SPACER 202 X-3359-416-1 CHASSIS ASSY, MECHANICAL * 203 3-359-415-01 SLIDER (TRIGGER SLIDER) 204 3-359-454-01 SPRING, TORSION 205 3-359-429-01 SLIDER (BRAKE PLATE) 206 3-359-456-01 SPRING (TRIGGER SPRING), TORSION 207 X-3366-569-1 ARM ASSY, FR Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 208 3-359-419-11 GEAR (FR GEAR) 209 3-359-421-01 CLUTCH (REEL DISK) 210 3-359-418-01 PULLEY (FR PULLEY) 211 3-924-185-11 SPRING (FR ARM), TORSION 212 3-936-483-01 GEAR (CAM GEAR) 213 3-359-448-01 GEAR (TRIGGER) (5) MECHANISM DECK SECTION-2 (TCM-190VB12CSS) 201 202 203 204 205 206 207 208 209 210 211 212 213 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 42 – SECTION 7 ELECTRICAL PARTS LIST NOTE: • Due to standardization, replacements in the parts list may be different from the parts speci- fied in the diagrams or the components used on the set. • -XX and -X mean standardized parts, so they may have some difference from the original one. • RESISTORS All resistors are in ohms. METAL: Metal-film resistor. METAL OXIDE: Metal oxide-film resistor. F: nonflammable • Items marked “*” are not stocked since they are seldom required for routine service. Some delay should be anticipated when order- ing these items. • SEMICONDUCTORS In each case, u: µ, for example: uA. . : µA. . uPA. . : µPA. . uPB. . : µPB. . uPC. . : µPC. . uPD. . : µPD. . • CAPACITORS uF: µF • COILS uH: µH The components identified by mark ! or dotted line with mark ! are critical for safety. Replace only with part number specified. When indicating parts by reference number, please include the board. Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark AC POWER SW AC POWER SW BOARD ******************* (Included in MAIN BOARD, COMPLETE) < CAPACITOR > !C713 1-117-703-11 CERAMIC 0.0047uF 99% 250V < SWITCH > !S930 1-762-581-11 SWITCH, AC POWER PUSH (1 KEY) (I/O) ************************************************************ * A-2007-780-A AUDIO BOARD, COMPLETE ********************** < CAPACITOR > C11 1-163-133-00 CERAMIC CHIP 470PF 5% 50V C12 1-136-157-00 FILM 0.022uF 5% 50V C13 1-124-234-00 ELECT 22uF 20% 16V C18 1-163-251-11 CERAMIC CHIP 100PF 5% 50V C21 1-163-133-00 CERAMIC CHIP 470PF 5% 50V C22 1-136-157-00 FILM 0.022uF 5% 50V C23 1-124-234-00 ELECT 22uF 20% 16V C28 1-163-251-11 CERAMIC CHIP 100PF 5% 50V C31 1-124-234-00 ELECT 22uF 20% 16V C32 1-124-234-00 ELECT 22uF 20% 16V C33 1-124-234-00 ELECT 22uF 20% 16V C51 1-164-182-11 CERAMIC CHIP 0.0033uF 10% 50V C52 1-164-182-11 CERAMIC CHIP 0.0033uF 10% 50V C53 1-163-020-00 CERAMIC CHIP 0.0082uF 10% 50V C54 1-136-601-11 FILM 0.01uF 5% 630V C56 1-164-505-11 CERAMIC CHIP 2.2uF 16V C57 1-164-346-11 CERAMIC CHIP 1uF 16V C71 1-164-346-11 CERAMIC CHIP 1uF 16V C80 1-124-234-00 ELECT 22uF 20% 16V C81 1-164-232-11 CERAMIC CHIP 0.01uF 50V C82 1-136-157-00 FILM 0.022uF 5% 50V C83 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V C84 1-136-439-11 FILM 330PF 5% 630V C85 1-136-433-11 FILM 100PF 5% 630V C86 1-163-143-00 CERAMIC CHIP 0.0012uF 5% 50V C87 1-136-273-00 FILM 75PF 5% 630V C88 1-163-003-11 CERAMIC CHIP 330PF 10% 50V C89 1-124-234-00 ELECT 22uF 20% 16V C90 1-107-584-11 CERAMIC 4PF 0.25PF 500V C91 1-164-232-11 CERAMIC CHIP 0.01uF 50V C92 1-136-157-00 FILM 0.022uF 5% 50V C93 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V C94 1-136-439-11 FILM 330PF 5% 630V C95 1-136-433-11 FILM 100PF 5% 630V C96 1-163-143-00 CERAMIC CHIP 0.0012uF 5% 50V C97 1-136-273-00 FILM 75PF 5% 630V C98 1-163-003-11 CERAMIC CHIP 330PF 10% 50V C99 1-164-005-11 CERAMIC CHIP 0.47uF 25V < CONNECTOR > * CNP31 1-580-782-11 CONNECTOR, BOARD TO BOARD * CNP32 1-580-781-11 PIN, CONNECTOR (PC BOARD) 7P * CNP33 1-580-782-11 CONNECTOR, BOARD TO BOARD * CNP71 1-564-719-11 PIN, CONNECTOR (SMALL TYPE) 3P CNP72 1-764-902-11 CONNECTOR, FFC/FPC 4P < DIODE > D31 8-719-404-46 DIODE MA110 < IC > IC31 8-759-711-85 IC NJM4580E-D IC81 8-759-106-56 IC uPC1297CA < COIL > L81 1-410-780-11 INDUCTOR 27mH L91 1-410-780-11 INDUCTOR 27mH < TRANSISTOR > Q51 8-729-822-05 TRANSISTOR 2SD1622-ST-TD Q52 8-729-822-05 TRANSISTOR 2SD1622-ST-TD Q53 8-729-822-05 TRANSISTOR 2SD1622-ST-TD Q71 8-729-602-36 TRANSISTOR 2SA1602 < RESISTOR > R11 1-216-086-00 RES, CHIP 36K 5% 1/10W R12 1-216-025-00 RES, CHIP 100 5% 1/10W R13 1-216-100-00 RES, CHIP 130K 5% 1/10W R14 1-216-068-00 METAL CHIP 6.2K 5% 1/10W R21 1-216-086-00 RES, CHIP 36K 5% 1/10W AUDIO www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 43 – Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark R22 1-216-025-00 RES, CHIP 100 5% 1/10W R23 1-216-100-00 RES, CHIP 130K 5% 1/10W R24 1-216-068-00 METAL CHIP 6.2K 5% 1/10W R31 1-216-033-00 METAL CHIP 220 5% 1/10W R32 1-216-033-00 METAL CHIP 220 5% 1/10W R33 1-216-065-91 RES, CHIP 4.7K 5% 1/10W R51 1-216-091-00 METAL CHIP 56K 5% 1/10W R52 1-216-091-00 METAL CHIP 56K 5% 1/10W R53 1-216-073-00 METAL CHIP 10K 5% 1/10W R54 1-216-309-00 METAL CHIP 5.6 5% 1/10W R55 1-216-309-00 METAL CHIP 5.6 5% 1/10W R57 1-216-298-00 METAL CHIP 2.2 5% 1/10W R71 1-216-025-00 RES, CHIP 100 5% 1/10W R72 1-216-055-00 METAL CHIP 1.8K 5% 1/10W R73 1-216-089-00 RES, CHIP 47K 5% 1/10W R74 1-216-089-00 RES, CHIP 47K 5% 1/10W R81 1-216-073-00 METAL CHIP 10K 5% 1/10W R82 1-216-085-00 METAL CHIP 33K 5% 1/10W R83 1-216-001-00 METAL CHIP 10 5% 1/10W R84 1-216-101-00 METAL CHIP 150K 5% 1/10W R85 1-216-075-00 METAL CHIP 12K 5% 1/10W R91 1-216-073-00 METAL CHIP 10K 5% 1/10W R92 1-216-085-00 METAL CHIP 33K 5% 1/10W R93 1-216-001-00 METAL CHIP 10 5% 1/10W R94 1-216-101-00 METAL CHIP 150K 5% 1/10W R95 1-216-075-00 METAL CHIP 12K 5% 1/10W < VARIABLE RESISTOR > RV11 1-241-761-11 RES, ADJ, CARBON 1K RV12 1-241-761-11 RES, ADJ, CARBON 1K RV71 1-241-761-11 RES, ADJ, CARBON 1K RV72 1-241-762-11 RES, ADJ, CARBON 2.2K RV81 1-241-786-11 RES, ADJ, CARBON 22K RV91 1-241-786-11 RES, ADJ, CARBON 22K < RELAY > RY31 1-515-913-11 RELAY < TRANSFORMER > T51 1-433-383-11 TRANSFORMER, BIAS OSCILLATION T81 1-433-398-11 TRANSFORMER, BIAS OSCILLATOR T91 1-433-398-11 TRANSFORMER, BIAS OSCILLATOR < TEST PIN > * TP81 1-568-449-11 HOUSING, CONNECTOR (PC BOARD) 3P (TEST TERMINAL) ************************************************************ * A-2007-481-A DOLBY-S BOARD, COMPLETE ************************ < CAPACITOR > C1 1-136-165-00 FILM 0.1uF 5% 50V C2 1-163-012-00 CERAMIC CHIP 0.0018uF 10% 50V C3 1-163-012-00 CERAMIC CHIP 0.0018uF 10% 50V C4 1-164-222-11 CERAMIC CHIP 0.22uF 25V C5 1-136-165-00 FILM 0.1uF 5% 50V C6 1-136-165-00 FILM 0.1uF 5% 50V C7 1-137-372-11 FILM 0.022uF 5% 50V C8 1-164-222-11 CERAMIC CHIP 0.22uF 25V C9 1-126-301-11 ELECT 1uF 20% 50V C10 1-137-442-11 FILM 0.039uF 5% 50V C11 1-163-007-11 CERAMIC CHIP 680PF 10% 50V C12 1-164-717-11 CERAMIC CHIP 0.0082uF 5% 50V C13 1-163-038-00 CERAMIC CHIP 0.1uF 25V C14 1-124-465-00 ELECT 0.47uF 20% 50V C15 1-164-222-11 CERAMIC CHIP 0.22uF 25V C16 1-163-038-00 CERAMIC CHIP 0.1uF 25V C17 1-124-465-00 ELECT 0.47uF 20% 50V C18 1-163-038-00 CERAMIC CHIP 0.1uF 25V C19 1-164-222-11 CERAMIC CHIP 0.22uF 25V C20 1-163-035-00 CERAMIC CHIP 0.047uF 50V C21 1-164-717-11 CERAMIC CHIP 0.0082uF 5% 50V C22 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 100V C23 1-163-005-11 CERAMIC CHIP 470PF 10% 50V C24 1-137-442-11 FILM 0.039uF 5% 50V C25 1-136-165-00 FILM 0.1uF 5% 50V C26 1-137-372-11 FILM 0.022uF 5% 50V C28 1-163-038-00 CERAMIC CHIP 0.1uF 25V < CONNECTOR > CN1 1-695-092-11 SOCKET, CONNECTOR 7P < IC > IC1 8-752-076-30 IC CXA1917AM-T6 < SHORT CHIP > J1 1-216-296-00 SHORT (CHIP) 0 J2 1-216-296-00 SHORT (CHIP) 0 J3 1-216-296-00 SHORT (CHIP) 0 < RESISTOR > R1 1-216-685-11 METAL CHIP 27K 0.5% 1/10W R2 1-208-811-11 RES, CHIP 16K 2% 1/10W R3 1-208-791-11 RES, CHIP 2.4K 2% 1/10W R4 1-208-799-11 RES, CHIP 5.1K 2% 1/10W R5 1-216-689-11 METAL CHIP 39K 0.5% 1/10W R6 1-216-689-11 METAL CHIP 39K 0.5% 1/10W R7 1-216-615-11 METAL CHIP 33 0.5% 1/10W R8 1-208-462-41 RES, CHIP 10K 2% 1/10W R9 1-208-812-11 RES, CHIP 18K 2% 1/10W R10 1-216-615-11 METAL CHIP 33 0.5% 1/10W R11 1-216-619-11 METAL CHIP 47 0.5% 1/10W R12 1-216-684-11 METAL CHIP 24K 0.5% 1/10W R13 1-216-615-11 METAL CHIP 33 0.5% 1/10W R14 1-216-619-11 METAL CHIP 47 0.5% 1/10W R15 1-216-655-11 METAL CHIP 1.5K 0.5% 1/10W R16 1-216-678-11 METAL CHIP 13K 0.5% 1/10W R17 1-216-673-11 METAL CHIP 8.2K 0.5% 1/10W R18 1-208-462-41 RES, CHIP 10K 2% 1/10W R19 1-208-462-41 RES, CHIP 10K 2% 1/10W R20 1-216-689-11 METAL CHIP 39K 0.5% 1/10W ************************************************************ DOLBY-S AUDIO www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 44 – Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark HP BOARD ********* (Included in MAIN BOARD, COMPLETE) < CAPACITOR > C133 1-162-294-31 CERAMIC 0.001uF 10% 50V C233 1-162-294-31 CERAMIC 0.001uF 10% 50V < JACK > J502 1-568-519-41 JACK, LARGE TYPE (PHONES) ************************************************************ * 1-638-020-11 LEAF SW BOARD ************** < CONNECTOR > * CNP81 1-568-850-11 SOCKET, CONNECTOR 7P CNP81 1-695-368-31 PIN, CONNECTOR (PC BOARD) 7P < IC > IC81 8-749-924-10 IC PHOTO REFLECTOR NJL5165K-B(H1) < RESISTOR > R81 1-249-414-11 CARBON 560 5% 1/4W R83 1-247-834-11 CARBON 1.3K 5% 1/4W R84 1-249-417-11 CARBON 1K 5% 1/4W R85 1-249-408-11 CARBON 180 5% 1/4W < SWITCH > S81 1-571-958-11 SWITCH, PUSH (1 KEY) (MECHANISM STOP) S82 1-571-281-21 SWITCH, LEAF (70u) S83 1-571-281-21 SWITCH, LEAF (METAL) S84 1-571-281-21 SWITCH, LEAF (REC) S86 1-571-281-21 SWITCH, LEAF (HALF) ************************************************************ * A-2007-779-A MAIN BOARD, COMPLETE ********************* (Including AC POWER SW BOARD, HP BOARD, PANEL BOARD, REC VOL BOARD, and TRANSFORMER BOARD) < CAPACITOR > C101 1-137-372-11 FILM 0.022uF 5% 50V C102 1-126-963-11 ELECT 4.7uF 20% 50V C103 1-137-368-11 FILM 0.0047uF 5% 50V C104 1-126-964-11 ELECT 10uF 20% 50V C105 1-136-165-00 FILM 0.1uF 5% 50V C106 1-136-163-00 FILM 0.068uF 5% 50V C107 1-126-965-11 ELECT 22uF 20% 50V C108 1-126-964-11 ELECT 10uF 20% 50V C109 1-126-964-11 ELECT 10uF 20% 50V C110 1-126-963-11 ELECT 4.7uF 20% 50V C111 1-126-962-11 ELECT 3.3uF 20% 50V C112 1-126-959-11 ELECT 0.47uF 20% 50V C113 1-126-963-11 ELECT 4.7uF 20% 50V C114 1-137-436-11 FILM 0.0039uF 5% 50V C115 1-137-366-11 FILM 0.0022uF 5% 50V C116 1-136-170-00 FILM 0.27uF 5% 50V C131 1-126-963-11 ELECT 4.7uF 20% 50V C132 1-126-962-11 ELECT 3.3uF 20% 50V C201 1-137-372-11 FILM 0.022uF 5% 50V C202 1-126-963-11 ELECT 4.7uF 20% 50V C203 1-137-368-11 FILM 0.0047uF 5% 50V C204 1-126-964-11 ELECT 10uF 20% 50V C205 1-136-165-00 FILM 0.1uF 5% 50V C206 1-136-163-00 FILM 0.068uF 5% 50V C207 1-126-965-11 ELECT 22uF 20% 50V C208 1-126-964-11 ELECT 10uF 20% 50V C209 1-126-964-11 ELECT 10uF 20% 50V C210 1-126-963-11 ELECT 4.7uF 20% 50V C211 1-126-962-11 ELECT 3.3uF 20% 50V C212 1-126-959-11 ELECT 0.47uF 20% 50V C213 1-126-963-11 ELECT 4.7uF 20% 50V C214 1-137-436-11 FILM 0.0039uF 5% 50V C215 1-137-366-11 FILM 0.0022uF 5% 50V C216 1-136-170-00 FILM 0.27uF 5% 50V C231 1-126-963-11 ELECT 4.7uF 20% 50V C232 1-126-962-11 ELECT 3.3uF 20% 50V C301 1-126-935-11 ELECT 470uF 20% 16V C501 1-126-935-11 ELECT 470uF 20% 16V C502 1-126-964-11 ELECT 10uF 20% 50V C503 1-126-964-11 ELECT 10uF 20% 50V C504 1-126-960-11 ELECT 1uF 20% 50V C505 1-126-964-11 ELECT 10uF 20% 50V C506 1-126-925-11 ELECT 470uF 20% 10V C511 1-137-374-11 FILM 0.047uF 5% 50V C512 1-136-164-00 FILM 0.082uF 5% 50V C513 1-137-367-11 FILM 0.0033uF 5% 50V C521 1-126-964-11 ELECT 10uF 20% 50V C551 1-162-282-31 CERAMIC 100PF 10% 50V C552 1-161-494-00 CERAMIC 0.022uF 25V C553 1-162-217-31 CERAMIC 56PF 5% 50V C554 1-126-961-11 ELECT 2.2uF 20% 50V C555 1-126-961-11 ELECT 2.2uF 20% 50V C571 1-126-961-11 ELECT 2.2uF 20% 50V C572 1-126-916-11 ELECT 1000uF 20% 6.3V C601 1-164-159-11 CERAMIC 0.1uF 50V C602 1-162-288-31 CERAMIC 330PF 10% 50V C701 1-126-943-11 ELECT 2200uF 20% 25V C702 1-126-943-11 ELECT 2200uF 20% 25V C703 1-104-664-11 ELECT 47uF 20% 25V C704 1-126-926-11 ELECT 1000uF 20% 10V C705 1-126-926-11 ELECT 1000uF 20% 10V C706 1-126-935-11 ELECT 470uF 20% 6.3V C707 1-126-964-11 ELECT 10uF 20% 50V C708 1-126-963-11 ELECT 4.7uF 20% 50V C709 1-126-968-11 ELECT 100uF 20% 50V C710 1-104-664-11 ELECT 47uF 20% 25V C711 1-164-159-11 CERAMIC 0.1uF 50V C801 1-126-963-11 ELECT 4.7uF 20% 50V C805 1-161-494-00 CERAMIC 0.022uF 25V C806 1-126-964-11 ELECT 10uF 20% 50V C807 1-126-935-11 ELECT 470uF 20% 6.3V C808 1-161-494-00 CERAMIC 0.022uF 25V C809 1-161-494-00 CERAMIC 0.022uF 25V HP LEAF SW MAIN www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 45 – Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark C810 1-162-282-31 CERAMIC 100PF 10% 50V C811 1-164-159-11 CERAMIC 0.1uF 50V C812 1-137-374-11 FILM 0.047uF 5% 50V < CONNECTOR > * CN81 1-568-826-11 SOCKET, CONNECTOR 7P CN101 1-695-087-11 PIN, CONNECTOR (PC BOARD) 7P CN201 1-695-087-11 PIN, CONNECTOR (PC BOARD) 7P * CN504 1-568-828-11 SOCKET, CONNECTOR 9P CN506 1-506-468-11 PIN, CONNECTOR 3P * CN801 1-568-845-11 SOCKET, CONNECTOR 31P * CNB31 1-691-916-21 CONNECTOR, BOARD TO BOARD * CNB33 1-691-916-21 CONNECTOR, BOARD TO BOARD CNE701 1-564-510-11 PLUG, CONNECTOR 7P CNE701 1-764-330-11 PIN, CONNECTOR (PCB)(V TYPE)7P < DIODE > D131 8-719-911-19 DIODE 1SS119 D132 8-719-911-19 DIODE 1SS119 D231 8-719-911-19 DIODE 1SS119 D232 8-719-911-19 DIODE 1SS119 D511 8-719-911-19 DIODE 1SS119 D512 8-719-911-19 DIODE 1SS119 D513 8-719-911-19 DIODE 1SS119 D551 8-719-911-19 DIODE 1SS119 D701 8-719-024-99 DIODE 11ES2-NTA2B D702 8-719-024-99 DIODE 11ES2-NTA2B D703 8-719-024-99 DIODE 11ES2-NTA2B D704 8-719-024-99 DIODE 11ES2-NTA2B D705 8-719-024-99 DIODE 11ES2-NTA2B D706 8-719-024-99 DIODE 11ES2-NTA2B D707 8-719-024-99 DIODE 11ES2-NTA2B D708 8-719-933-33 DIODE HZS6A1L D709 8-719-986-05 DIODE HZS9A2LTA D710 8-719-985-88 DIODE HZS6B2LTA D711 8-719-911-19 DIODE 1SS119 D712 8-719-911-19 DIODE 1SS119 D713 8-719-986-00 DIODE HZS7C1LTA D714 8-719-911-19 DIODE 1SS119 D715 8-719-985-41 DIODE HZS2CLL D801 8-719-933-33 DIODE HZS6A1L D802 8-719-933-33 DIODE HZS6A1L < IC > IC501 8-752-066-35 IC CXA1563S IC502 8-752-055-62 IC CXA1579P IC503 8-759-634-51 IC M5218AP IC504 8-759-634-51 IC M5218AP IC505 8-759-634-51 IC M5218AP IC506 8-759-140-53 IC uPD4053BC IC507 8-759-634-51 IC M5218AP IC508 8-759-000-48 IC MC14052BCP IC509 8-759-916-14 IC SN74HC04AN IC510 8-759-634-51 IC M5218AP IC511 8-759-634-51 IC M5218AP IC512 8-759-634-51 IC M5218AP IC601 8-759-803-42 IC LA6500-FA IC701 8-759-634-51 IC M5218AP IC801 8-752-856-27 IC CXP82612-022Q IC802 8-759-165-82 IC PST600E-T < JACK > J501 1-784-430-11 JACK, PIN 4P (LINE IN, OUT) < FILTER > LPF101 1-233-271-11 FILTER, LOW PASS LPF201 1-233-271-11 FILTER, LOW PASS < TRANSISTOR > Q101 8-729-900-89 TRANSISTOR DTC144ES Q102 8-729-900-80 TRANSISTOR DTC114ES Q103 8-729-900-80 TRANSISTOR DTC114ES Q121 8-729-922-37 TRANSISTOR 2SD2144S Q122 8-729-119-78 TRANSISTOR 2SC403SP-51 Q201 8-729-900-89 TRANSISTOR DTC144ES Q202 8-729-900-80 TRANSISTOR DTC114ES Q203 8-729-900-80 TRANSISTOR DTC114ES Q221 8-729-922-37 TRANSISTOR 2SD2144S Q222 8-729-119-78 TRANSISTOR 2SC403SP-51 Q503 8-729-422-57 TRANSISTOR UN4111 Q511 8-729-119-78 TRANSISTOR 2SC403SP-51 Q512 8-729-900-74 TRANSISTOR DTC143TS Q521 8-729-900-80 TRANSISTOR DTC114ES Q531 8-729-422-57 TRANSISTOR UN4111 Q532 8-729-900-80 TRANSISTOR DTC114ES Q551 8-729-119-76 TRANSISTOR 2SA1175-HFE Q572 8-729-422-57 TRANSISTOR UN4111 Q573 8-729-900-65 TRANSISTOR DTA144ES Q601 8-729-801-93 TRANSISTOR 2SD1387 Q701 8-729-141-83 TRANSISTOR 2SB1094-LK Q702 8-729-209-15 TRANSISTOR 2SD2012 Q704 8-729-141-83 TRANSISTOR 2SB1094-LK Q705 8-729-119-78 TRANSISTOR 2SC403SP-51 Q707 8-729-119-76 TRANSISTOR 2SA1175-HFE Q708 8-729-140-04 TRANSISTOR 2SB1116A-L Q805 8-729-119-76 TRANSISTOR 2SA1175-HFE < RESISTOR > R101 1-247-838-00 CARBON 2K 5% 1/4W R102 1-247-843-11 CARBON 3.3K 5% 1/4W R104 1-249-417-11 CARBON 1K 5% 1/4W R105 1-249-420-11 CARBON 1.8K 5% 1/4W R106 1-247-887-00 CARBON 220K 5% 1/4W R107 1-247-846-11 CARBON 4.3K 5% 1/4W R108 1-249-429-11 CARBON 10K 5% 1/4W R110 1-249-429-11 CARBON 10K 5% 1/4W R111 1-249-427-11 CARBON 6.8K 5% 1/4W R112 1-247-864-11 CARBON 24K 5% 1/4W R113 1-249-429-11 CARBON 10K 5% 1/4W R114 1-249-437-11 CARBON 47K 5% 1/4W R115 1-249-433-11 CARBON 22K 5% 1/4W R116 1-249-434-11 CARBON 27K 5% 1/4W R121 1-249-437-11 CARBON 47K 5% 1/4W R122 1-249-421-11 CARBON 2.2K 5% 1/4W MAIN www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 46 – Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark R123 1-249-421-11 CARBON 2.2K 5% 1/4W R124 1-249-437-11 CARBON 47K 5% 1/4W R125 1-249-425-11 CARBON 4.7K 5% 1/4W R131 1-249-425-11 CARBON 4.7K 5% 1/4W R132 1-247-822-11 CARBON 430 5% 1/4W R133 1-247-866-11 CARBON 30K 5% 1/4W R134 1-249-435-11 CARBON 33K 5% 1/4W R135 1-249-439-11 CARBON 68K 5% 1/4W R136 1-249-410-11 CARBON 270 5% 1/4W R141 1-249-432-11 CARBON 18K 5% 1/4W R143 1-249-432-11 CARBON 18K 5% 1/4W R144 1-247-848-11 CARBON 5.1K 5% 1/4W R145 1-249-409-11 CARBON 220 5% 1/4W R151 1-249-433-11 CARBON 22K 5% 1/4W R152 1-249-417-11 CARBON 1K 5% 1/4W R153 1-249-441-11 CARBON 100K 5% 1/4W R154 1-249-433-11 CARBON 22K 5% 1/4W R201 1-247-838-00 CARBON 2K 5% 1/4W R202 1-247-843-11 CARBON 3.3K 5% 1/4W R204 1-249-417-11 CARBON 1K 5% 1/4W R205 1-249-420-11 CARBON 1.8K 5% 1/4W R206 1-247-887-00 CARBON 220K 5% 1/4W R207 1-247-846-11 CARBON 4.3K 5% 1/4W R208 1-249-429-11 CARBON 10K 5% 1/4W R210 1-249-429-11 CARBON 10K 5% 1/4W R211 1-249-427-11 CARBON 6.8K 5% 1/4W R212 1-247-864-11 CARBON 24K 5% 1/4W R213 1-249-429-11 CARBON 10K 5% 1/4W R214 1-249-437-11 CARBON 47K 5% 1/4W R215 1-249-433-11 CARBON 22K 5% 1/4W R216 1-249-434-11 CARBON 27K 5% 1/4W R221 1-249-437-11 CARBON 47K 5% 1/4W R222 1-249-421-11 CARBON 2.2K 5% 1/4W R223 1-249-421-11 CARBON 2.2K 5% 1/4W R224 1-249-437-11 CARBON 47K 5% 1/4W R225 1-249-425-11 CARBON 4.7K 5% 1/4W R231 1-249-425-11 CARBON 4.7K 5% 1/4W R232 1-247-822-11 CARBON 430 5% 1/4W R233 1-247-866-11 CARBON 30K 5% 1/4W R234 1-249-435-11 CARBON 33K 5% 1/4W R235 1-249-439-11 CARBON 68K 5% 1/4W R236 1-249-410-11 CARBON 270 5% 1/4W R241 1-249-432-11 CARBON 18K 5% 1/4W R243 1-249-432-11 CARBON 18K 5% 1/4W R244 1-247-848-11 CARBON 5.1K 5% 1/4W R245 1-249-409-11 CARBON 220 5% 1/4W R251 1-249-433-11 CARBON 22K 5% 1/4W R252 1-249-417-11 CARBON 1K 5% 1/4W R253 1-249-441-11 CARBON 100K 5% 1/4W R254 1-249-433-11 CARBON 22K 5% 1/4W !R502 1-215-452-00 METAL 20K 1% 1/4W F !R503 1-215-455-00 METAL 27K 1% 1/4W F R505 1-249-417-11 CARBON 1K 5% 1/4W R512 1-249-421-11 CARBON 2.2K 5% 1/4W R513 1-249-441-11 CARBON 100K 5% 1/4W R514 1-249-441-11 CARBON 100K 5% 1/4W R515 1-249-436-11 CARBON 39K 5% 1/4W R516 1-249-425-11 CARBON 4.7K 5% 1/4W R517 1-249-433-11 CARBON 22K 5% 1/4W R518 1-249-425-11 CARBON 4.7K 5% 1/4W R521 1-249-426-11 CARBON 5.6K 5% 1/4W R522 1-249-426-11 CARBON 5.6K 5% 1/4W R523 1-247-858-11 CARBON 13K 5% 1/4W R524 1-247-852-11 CARBON 7.5K 5% 1/4W R525 1-247-854-11 CARBON 9.1K 5% 1/4W R526 1-247-854-11 CARBON 9.1K 5% 1/4W R527 1-249-426-11 CARBON 5.6K 5% 1/4W R528 1-249-422-11 CARBON 2.7K 5% 1/4W R529 1-249-429-11 CARBON 10K 5% 1/4W R530 1-249-421-11 CARBON 2.2K 5% 1/4W R531 1-249-426-11 CARBON 5.6K 5% 1/4W R532 1-247-864-11 CARBON 24K 5% 1/4W R535 1-249-419-11 CARBON 1.5K 5% 1/4W R536 1-249-421-11 CARBON 2.2K 5% 1/4W R537 1-247-866-11 CARBON 30K 5% 1/4W R538 1-247-852-11 CARBON 7.5K 5% 1/4W R539 1-249-431-11 CARBON 15K 5% 1/4W R540 1-247-874-11 CARBON 62K 5% 1/4W R541 1-249-429-11 CARBON 10K 5% 1/4W R542 1-249-429-11 CARBON 10K 5% 1/4W R543 1-249-429-11 CARBON 10K 5% 1/4W R544 1-249-429-11 CARBON 10K 5% 1/4W R553 1-249-437-11 CARBON 47K 5% 1/4W R555 1-249-427-11 CARBON 6.8K 5% 1/4W R556 1-247-843-11 CARBON 3.3K 5% 1/4W R557 1-249-441-11 CARBON 100K 5% 1/4W R558 1-249-429-11 CARBON 10K 5% 1/4W R559 1-249-441-11 CARBON 100K 5% 1/4W R560 1-249-417-11 CARBON 1K 5% 1/4W R561 1-249-432-11 CARBON 18K 5% 1/4W R562 1-249-436-11 CARBON 39K 5% 1/4W R572 1-249-429-11 CARBON 10K 5% 1/4W R573 1-249-429-11 CARBON 10K 5% 1/4W R574 1-249-435-11 CARBON 33K 5% 1/4W R575 1-247-807-31 CARBON 100 5% 1/4W R576 1-249-435-11 CARBON 33K 5% 1/4W R577 1-249-429-11 CARBON 10K 5% 1/4W R578 1-249-433-11 CARBON 22K 5% 1/4W R601 1-249-419-11 CARBON 1.5K 5% 1/4W R602 1-249-429-11 CARBON 10K 5% 1/4W R603 1-247-807-31 CARBON 100 5% 1/4W R604 1-249-433-11 CARBON 22K 5% 1/4W R605 1-249-433-11 CARBON 22K 5% 1/4W R606 1-249-430-11 CARBON 12K 5% 1/4W R607 1-249-433-11 CARBON 22K 5% 1/4W R608 1-247-862-11 CARBON 20K 5% 1/4W R609 1-249-429-11 CARBON 10K 5% 1/4W R701 1-249-425-11 CARBON 4.7K 5% 1/4W R702 1-249-419-11 CARBON 1.5K 5% 1/4W R703 1-249-418-11 CARBON 1.2K 5% 1/4W R704 1-249-427-11 CARBON 6.8K 5% 1/4W R705 1-249-419-11 CARBON 1.5K 5% 1/4W R706 1-249-419-11 CARBON 1.5K 5% 1/4W R707 1-249-429-11 CARBON 10K 5% 1/4W R708 1-249-425-11 CARBON 4.7K 5% 1/4W MAIN The components identified by mark ! or dotted line with mark ! are critical for safety. Replace only with part num- ber specified. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 47 – Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark R709 1-249-409-11 CARBON 220 5% 1/4W R710 1-249-417-11 CARBON 1K 5% 1/4W R711 1-249-427-11 CARBON 6.8K 5% 1/4W R712 1-249-427-11 CARBON 6.8K 5% 1/4W R713 1-249-421-11 CARBON 2.2K 5% 1/4W R715 1-249-421-11 CARBON 2.2K 5% 1/4W R716 1-249-437-11 CARBON 47K 5% 1/4W R717 1-249-429-11 CARBON 10K 5% 1/4W R718 1-247-870-11 CARBON 43K 5% 1/4W R719 1-249-429-11 CARBON 10K 5% 1/4W R801 1-249-417-11 CARBON 1K 5% 1/4W R802 1-249-441-11 CARBON 100K 5% 1/4W R803 1-249-429-11 CARBON 10K 5% 1/4W R805 1-249-434-11 CARBON 27K 5% 1/4W R806 1-249-434-11 CARBON 27K 5% 1/4W R807 1-249-434-11 CARBON 27K 5% 1/4W R808 1-249-434-11 CARBON 27K 5% 1/4W R809 1-249-434-11 CARBON 27K 5% 1/4W R810 1-247-807-31 CARBON 100 5% 1/4W R811 1-247-807-31 CARBON 100 5% 1/4W R812 1-247-807-31 CARBON 100 5% 1/4W R813 1-247-807-31 CARBON 100 5% 1/4W R814 1-247-807-31 CARBON 100 5% 1/4W R815 1-247-807-31 CARBON 100 5% 1/4W R816 1-247-807-31 CARBON 100 5% 1/4W R821 1-249-429-11 CARBON 10K 5% 1/4W R822 1-249-429-11 CARBON 10K 5% 1/4W R823 1-249-429-11 CARBON 10K 5% 1/4W R824 1-249-421-11 CARBON 2.2K 5% 1/4W R825 1-249-435-11 CARBON 33K 5% 1/4W R826 1-249-421-11 CARBON 2.2K 5% 1/4W R827 1-249-422-11 CARBON 2.7K 5% 1/4W R828 1-249-422-11 CARBON 2.7K 5% 1/4W R829 1-249-422-11 CARBON 2.7K 5% 1/4W R830 1-249-429-11 CARBON 10K 5% 1/4W R831 1-249-429-11 CARBON 10K 5% 1/4W R832 1-249-437-11 CARBON 47K 5% 1/4W R833 1-249-437-11 CARBON 47K 5% 1/4W < VARIABLE RESISTOR > RV111 1-241-765-11 RES, ADJ, CARBON 22K RV211 1-241-765-11 RES, ADJ, CARBON 22K < TEST PIN > * TP801 1-560-060-00 PIN, CONNECTOR 2P (TEST TERMINAL) < VIBRATOR > X801 1-577-360-11 VIBRATOR, CERAMIC (6MHz) ************************************************************ PANEL BOARD ************ (Included in MAIN BOARD, COMPLETE) * 3-377-337-11 HOLDER (FL) < CAPACITOR > C901 1-104-665-11 ELECT 100uF 20% 10V < CONNECTOR > * CN901 1-568-845-11 SOCKET, CONNECTOR 31P < FILTER > FL901 1-517-374-11 INDICATOR TUBE, FLUORESCENT < IC > IC901 8-749-014-66 IC NJL56H400 < RESISTOR > R902 1-247-848-11 CARBON 5.1K 5% 1/4W R903 1-249-426-11 CARBON 5.6K 5% 1/4W R904 1-249-429-11 CARBON 10K 5% 1/4W R905 1-249-435-11 CARBON 33K 5% 1/4W R906 1-249-420-11 CARBON 1.8K 5% 1/4W R907 1-247-843-11 CARBON 3.3K 5% 1/4W R908 1-249-426-11 CARBON 5.6K 5% 1/4W R927 1-247-807-31 CARBON 100 5% 1/4W R928 1-247-807-31 CARBON 100 5% 1/4W < SWITCH > S901 1-572-184-11 SWITCH, KEYBOARD (p) S902 1-572-184-11 SWITCH, KEYBOARD (AMS, 0) S903 1-572-184-11 SWITCH, KEYBOARD (AMS, )) S904 1-572-184-11 SWITCH, KEYBOARD (r, REC) S905 1-572-184-11 SWITCH, KEYBOARD (R, REC MUTING) S906 1-572-184-11 SWITCH, KEYBOARD (·) S907 1-572-184-11 SWITCH, KEYBOARD (P, PAUSE) S908 1-572-184-11 SWITCH, KEYBOARD (MEMORY) S909 1-572-184-11 SWITCH, KEYBOARD (RESET) ************************************************************ REC VOL BOARD ************** (Included in MAIN BOARD, COMPLETE) < CONNECTOR > * CN904 1-568-828-11 SOCKET, CONNECTOR 9P < RESISTOR > R921 1-249-430-11 CARBON 12K 5% 1/4W R922 1-249-427-11 CARBON 6.8K 5% 1/4W R923 1-247-843-11 CARBON 3.3K 5% 1/4W R924 1-247-868-11 CARBON 36K 5% 1/4W R925 1-247-836-11 CARBON 1.6K 5% 1/4W R926 1-249-421-11 CARBON 2.2K 5% 1/4W < VARIABLE RESISTOR > RV901 1-225-607-11 RES, VAR, CARBON 10K/10K (REC LEVEL) RV902 1-223-605-11 RES, VAR, CARBON 20K/20K (BALANCE) < SWITCH > S921 1-572-184-11 SWITCH, KEYBOARD (AUTO CAL) S922 1-762-647-11 SWITCH, ROTARY (DOLBY NR) ************************************************************ MAIN PANEL REC VOL www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 48 – Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark TRANSFORMER BOARD ******************* (Included in MAIN BOARD, COMPLETE) * 3-923-762-11 HOLDER (TR) < CAPACITOR > C712 1-161-494-00 CERAMIC 0.022uF 25V C714 1-136-169-00 FILM 0.22uF 5% 50V C715 1-136-169-00 FILM 0.22uF 5% 50V < CONNECTOR > * CN702 1-580-230-31 PIN, CONNECTOR (PC BOARD) 2P CN704 1-568-226-11 PIN, CONNECTOR 2P ************************************************************ MISCELLANEOUS ************** !7 1-575-651-21 CORD, POWER (AEP) !7 1-696-586-11 CORD, POWER (UK) !7 1-696-845-11 CORD, POWER (Australian) 59 1-696-456-11 WIRE (FLAT TYPE) (31 CORE) 60 1-590-486-11 WIRE (FLAT TYPE) (7 CORE) 103 1-769-914-11 WIRE (FLAT TYPE)(9 CORE) 152 A-2004-673-A DECK (ONE) ASSY, HEAD (including HRP901) 161 1-638-983-11 MOTOR FLEXIBLE BOARD M901 X-3363-501-2 MOTOR ASSY (REEL) M902 X-3374-302-1 MOTOR ASSY (CAPSTAN) !T901 1-427-751-11 TRANSFORMER, POWER ************************************************************ ************** HARDWARE LIST ************** #1 7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S #2 7-685-885-09 SCREW +BVTT 4X16 (S) #3 7-685-863-09 SCREW +BVTT 2.6X8 (S) #4 7-685-134-19 SCREW +PTPWH 2.6X8 (TYPE2) #5 7-685-862-09 SCREW +BVTT 2.6X6 (S) #6 7-621-772-58 SCREW (+B 2X10) #7 7-621-775-00 SCREW +B 2.6X3 #8 7-627-556-08 SCREW +P 2.6X2.8 ************************************************************ ACCESSORIES & PACKING MATERIALS ******************************* 1-776-263-11 CORD, CONNECTION (AUDIO) 1.5m 3-861-966-11 MANUAL, INSTRUCTIONS (ENGLISH, FRENCH, SPANISH, PORTUGUESE) 3-861-966-21 MANUAL, INSTRUCTIONS (GERMAN, DUTCH, SWEDISH, ITALIAN) (AEP) TRANSFORMER TC-KB820S Sony Corporation Home A&V Products Company 9-922-817-11 98D0553-1 Printed in Japan © 1998.4 Published by Quality Assurance Dept. (Shibaura) The components identified by mark ! or dotted line with mark ! are critical for safety. Replace only with part num- ber specified. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com
