– 1 – SERVICE MANUAL US Model Canadian Model AEP Model UK Model E Model Australian Model Chinese Model STEREO CASSETTE DECK MICROFILM SPECIFICATIONS Dolby noise reduction extension manufactured under license from Dolby Laboratories Licensing Corporation. HX Pro originated by Bang & Olufsen. “DOLBY”, the double-D symbol a and “HX PRO” are trademarks of Dolby Laboratories Licensing Corporation. TC-WE635 — Continued on next page — Model Name Using Similar Mechanism TC-WE425/WE525/WR681 Transport Mechanism Type TCM-230ASR4/HSR4 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 2 – SAFETY-RELATED COMPONENT WARNING!! COMPONENTS IDENTIFIED BY MARK ! OR DOTTED LINE WITH MARK ! ON THE SCHEMATIC DIAGRAMS AND IN THE PARTS LIST ARE CRITICAL TO SAFE OPERATION. REPLACE THESE COMPONENTS WITH SONY PARTS WHOSE PART NUMBERS APPEAR AS SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUBLISHED BY SONY. ATTENTION AU COMPOSANT AYANT RAPPORT À LA SÉCURITÉ!! LES COMPOSANTS IDENTIFIÉS PAR UNE MARQUE ! SUR LES DIAGRAMMES SCHÉMATIQUES ET LA LISTE DES PIÈCES SONT CRITIQUES POUR LA SÉCURITÉ DE FONCTIONNEMENT. NE REMPLACER CES COMPOSANTS QUE PAR DES PIÈCES SONY DONT LES NUMÉROS SONT DONNÉS DANS CE MANUEL OU DANS LES SUPPLÉMENTS PUBLIÉS PAR SONY. SAFETY CHECK-OUT After correcting the original service problem, perform the follow- ing safety checks before releasing the set to the customer: Check the antenna terminals, metal trim, “metallized” knobs, screws, and all other exposed metal parts for AC leakage. Check leakage as described below. LEAKAGE The AC leakage from any exposed metal part to earth Ground and from all exposed metal parts to any exposed metal part having a return to chassis, must not exceed 0.5 mA (500 microampers). Leak- age current can be measured by any one of three methods. 1. A commercial leakage tester, such as the Simpson 229 or RCA WT-540A. Follow the manufacturers’ instructions to use these instruments. 2. A battery-operated AC milliammeter. The Data Precision 245 digital multimeter is suitable for this job. 3. Measuring the voltage drop across a resistor by means of a VOM or battery-operated AC voltmeter. The “limit” indication is 0.75 V, so analog meters must have an accurate low-voltage scale. The Simpson 250 and Sanwa SH-63Trd are examples of a pas- sive VOM that is suitable. Nearly all battery operated digital multimeters that have a 2V AC range are suitable. (See Fig. A) Fig. A. Using an AC voltmeter to check AC leakage. 0.15µF To Exposed Metal Parts on Set 1.5kΩ AC voltmeter (0.75V) Earth Ground www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 3 – MODEL IDENTIFICATION –Back panel– PARTS No. MODEL 3-032-412-0π US model 3-032-412-1π CND model 3-032-412-2π AEP model 3-032-412-3π UK model 3-032-412-4π AUS model 3-032-412-5π SP, MY model 3-032-412-6π CH model • Abbreviation CND : Canadian model SP : Singapore model MY : Malaysia model AUS : Australian model CH : Chinese model TABLE OF CONTENTS 1. GENERAL .......................................................................... 4 2. DISASSEMBLY 2-1. Case ...................................................................................... 5 2-2. Front Panel Assembly ........................................................... 5 2-3. Cassette Lid Assembly (Deck A/B) ...................................... 6 2-4. Mechanism Deck Assembly (Deck A/B) .............................. 6 2-5. Leaf SW (REC/PB) Board (Deck A/B) ................................ 7 2-6. Pinch Lever (FWD)/(REV) Assembly (Deck A/B)............... 8 2-7. Flywheel (FWD)/(REV) Assembly (Deck A/B) ................... 8 2-8. Mechanical Block Assembly (Deck A/B) ............................. 9 2-9. Head Relay (REC/PB) Board (Deck A/B) ............................ 9 3. SERVICE MODE ............................................................ 10 4. MECHANICAL ADJUSTMENTS ............................... 11 5. ELECTRICAL ADJUSTMENTS ............................... 11 6. DIAGRAMS 6-1. Circuit Boards Location ...................................................... 15 6-2. Printed Wiring Board – Main Section – .............................. 17 6-3. Schematic Diagram – Main Section – (1/4)........................ 19 6-4. Schematic Diagram – Main Section – (2/4)........................ 21 6-5. Schematic Diagram – Main Section – (3/4)........................ 23 6-6. Schematic Diagram – Main Section – (4/4)........................ 25 6-7. Printed Wiring Board – Deck Section – .............................. 27 6-8. Schematic Diagram – Deck Section – ................................ 28 6-9. Schematic Diagram – Display Section – ............................ 29 6-10. Printed Wiring Board – Display Section – ....................... 31 6-11. Schematic Diagram – Panel Section – .............................. 33 6-12. Printed Wiring Board – Panel Section – ........................... 35 6-13. Schematic Diagram – Power Section – ............................. 37 6-14. Printed Wiring Board – Power Section – ......................... 39 6-15. IC Pin Function ................................................................ 41 7. EXPLODED VIEWS 7-1. Case Section ........................................................................ 43 7-2. Chassis Section ................................................................... 44 7-3. Cassette Holder Section ...................................................... 45 7-4. Front Panel Section ............................................................. 46 7-5. Tape Mechanism Section (TCM-230ASR4/HSR4) ............ 47 8. ELECTRICAL PARTS LIST ........................................ 48 Part No. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 4 – SECTION 1 GENERAL LOCATION OF PARTS AND CONTROLS 1 U button 2 RESET (Deck A) button 3 MEMORY (Deck A) button 4 RESET (Deck B) button 5 MEMORY (Deck B) button 6 AUTO REC LEVEL indicator 7 REC LEVEL knob 8 FADER button 9 ARL button 10 SYNCHRO button 11 PHONES jack 12 HIGH/NOMAL button 13 A+B REC button 14 DECK B button 15 DECK A button 16 (AMS) ) (Deck B) button 17 0 (AMS) (Deck B) button 18 · (Deck B) button 19 ª (Deck B) button 20 REC r (Deck B) button 21 § (Eject) (Deck B) button Front Panel 22 REC MUTING R (Deck B) button 23 PAUSE P (Deck B) button 24 p (Deck B) button 25 DOLBY NR B/C switch 26 DOLBY NR OFF/ON FILTER 27 ·/FRONT (Deck A) button 28 ª/BACK (Deck A) button 29 REC r (Deck B) button 30 REC MUTING R (Deck A) button 31 § (Eject) (Deck A) button 32 PAUSE P (Deck A) button 33 p/CLEAR (Deck A) button 34 (AMS) ) (Deck A) button 35 0 (AMS) (Deck A) button 36 DISPLAY button 37 CHECK button 38 SET button 39 RMS/START button 40 PITCH CONTROL knob 41 PITCH CONTROL button 42 DIRECTION switch • AMS is the abbreviation for Automatic Music Sensor. 10 8 9 2 4 6 7 1 3 5 23 21 22 20 11 13 14 15 12 16 18 19 17 24 25 26 27 28 29 30 31 33 32 34 35 36 37 38 39 40 41 42 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 5 – SECTION 2 DISASSEMBLY Note : Follow the disassembly procedure in the numerical order given. 2-1. CASE 2-2. FRONT PANEL ASSEMBLY 1 Screw (BVTP 3x8) 2 Two Screws (Case 3 TP2) 3 Two Screws (Case 3 TP2) 4 Case !™ Screw (BVTP 3x8) !¢ Screw (BVTP 3x8) !£ Screw (BVTP 3x8) !¶ Two screws (BVTT 3x6) !§ Claw !∞ Claw !• Front panel assy 9 CN1002 0 CN1003 2 CN807 1 CN5802 3 CN803 4 CNA806 5 Flat type wire (Deck A) !¡ CN002 6 Flat type wire (Deck B) 7 Screw (BVTP 3x8) 8Wire www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 6 – 2-3. CASSETTE LID ASSEMBLY (DECK A/B) 2-4. MECHANISM DECK ASSEMBLY (DECK A/B) 2 Four claws 1 Push the EJECT button. 3 Cassette lid assy 1 Two screws (BVTP 2.6x8) 3 Mechanism deck assy 2 Two screws (BVTP 2.6x8) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 7 – 2-5. LEAF SW (REC/PB) BOARD (DECK A/B) 1 Two screws (PS 2.6x6) 2 Capstan motor assy 8 Belt (capstan) 3 Wires 5 Screw (BVTT 2x4) 4 Screw (BVTT 2x4) 6 Claws Claws 7 LEAF SW (REC/PB) board When installing, pull the belt (capstan) put around claws. a a b b www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 8 – 2-6. PINCH LEVER (FWD)/(REV) ASSEMBLY (DECK A/B) 2-7. FLYWHEEL (FWD)/(REV) ASSEMBLY (DECK A/B) 4 Pinch lever (FWD) assy 2 Pinch lever (REV) assy 1 Claw 3 Claw 1 Belt (FR2) 3 Flywheel (FWD) assy 6 Flywheel (REV) assy 4 Washer 7 Washer 2 Stopper washer 5 Stopper washer www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 9 – 2-8. MECHANICAL BLOCK ASSEMBLY (DECK A/B) 2-9. HEAD RELAY (REC/PB) BOARD (DECK A/B) 2 Two screws (BVTT 2x3.5) 1 Torsion spring 5 Reverse slider 4 Mechanical block assy 3 Two screws (BVTT 2x3.5) 3 Tension spring (HEAD) 2 HEAD RELAY (REC/PB) board 1 Screw (BVTT 2x4) 4 Head deck assy www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 10 – RESET 0 MEMORY 1 RMS/START 2 SET 3 CHECK 4 DISPLAY 5 0 (AMS) 6 (AMS) ) 7 p/CLEAR Grid check display (*1) 9/BACK 8 (/FRONT 9 PAUSE P A REC MUTING R b REC r C DIRECTION MODE switch A ª d PLAY RELAY · A deck side Button Display KEY CHECK & DISPLAY CHECK MODE While pressing the ª/BACK (A deck) and REC MUTING R (B deck) buttons with the power off, press the U button to turn on the power. The fluorescent display tube displays the number or special message corresponding to the button pressed. The message displayed differs according to the position of the switch. SECTION 3 SERVICE MODE RESET 0 MEMORY 1 DECK A 2 DECK B 3 A+B REC 4 HIGH/NOMAL 5 0 (AMS) 6 (AMS) ) 7 p Segment check display (*2) ª 8 · 9 PAUSE P A REC MUTING R b REC r C FADER d ARL E SYNCHRO All lit DOLBY NR switch (*3) OFF ª B PLAY C · B deck side Button Display Grit check display (*1) Segment check display (*2) RMS (*3) The DOLBY NR switch consists of a pair of switches. B and C are valid only in the ON or ON FILTER state. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 11 – PRECAUTION 1. Clean the following parts with a denatured alcohol-moistened swab : record/playback/erase head pinch roller rubber belts capstan idlers 2. Demagnetize the record/playback head with a head demagne- tizer. 3. Do not use a magnetized screwdriver for the adjustment. 4. After the adjustments, apply suitable locking compound to the parts adjusted. 5. The adjustments should be performed with the rated power sup- ply voltage unless otherwise noted. Torque Measurement SECTION 5 ELECTRICAL ADJUSTMENTS SECTION 4 MECHANICAL ADJUSTMENTS PRECAUTION 1. The adjustment should be performed in the publication. (Be sure to male playback adjustment at first.) 2. The adjustments and measurement should be performed for both L-CH and R-CH. • Switch position DOLBY NR switch : OFF DIRECTION MODE switch : A • Standard record position : Deliver the standard input signal level to input jack and set the REC LEVEL knob to obtain the standard output signal level as follows. – Record Mode– 0 dB = 0.775 V Standard Input Level Test Mode 1. While pressing the ·/FRONT (DECK A) and REC MUT- ING R buttons with the power off, press the U button to turn on the power. The fluorescent display tube lights up for about one second, and the test mode is set. The test mode performs the following two special functions. • Playback speed switching function Pressing the HIGH/NORMAL button switches the playback speed between standard/double speed. • Counter RESET & MEMORY function Resets the counter when recording starts. When rewound with the 0 (AMS) button after recording, stops at the point where recording started. 2. To release the test mode, turn OFF the power switch. Mode Torque meter Meter reading Forward CQ-102C 30 to 65 g • cm (0.42 to 0.90 oz • inch) Forward back tension CQ-102C DECK A : 1 to 6 g • cm (0.014 to 0.083 oz • inch) DECK B : 2 to 9 g • cm (0.028 to 0.125 oz • inch) Reverse CQ-102RC 30 to 65 g • cm (0.42 to 0.90 oz • inch) Reverse back tension CQ-102RC 1 to 6 g • cm (0.014 to 0.083 oz • inch) FF/REW CQ-201B 70 to 120 g • cm (0.97 to 1.67 oz • inch) set – + AF OSC attenuator 10 kΩ 600 Ω LINE IN level meter LINE OUT 47 kΩ Standard Output Level Test Tape Input terminal LINE IN source impedance 10 kΩ input signal level 0.5 V (–3.8 dB) Input terminal LINE IN source impedance 10 kΩ input signal level 0.5 V (–3.8 dB) Tape Contents Use P-4-A100 10 kHz, –10 dB Azimuth Adjustment WS-48B 3 kHz, 0 dB Tape Speed Adjustment P-4-L300 315 Hz, 0 dB PB Level Adjustment www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 12 – Record/Playback Head Azimuth Adjustment DECK A DECK B Procedure: 1. Forward Playback Mode 2. Turn the adjustment screw for the maximum output levels. If these levels do not match, turn the adjustment screw until both of output levels match together within 1 dB. 3. Playback Mode 4. Change the reverse playback mode and repeat the steps 1 to 3. 5. After the adjustment, lock the adjustment screws with suitable locking compound. Adjustment Location: – record/playback head – Tape speed Adjustment DECK A DECK B Adjust DECK A first Procedure: – Forward Playback Mode – (High speed adjustment) 1. Press the PITCH CONTROL button to set to OFF . 2. Set to test mode. (Refer to page 11.) 3. Press the · button to playback. 4. Press the HIGH/NORMAL button to playback at double speed. 5. Adjust RV316 (DECK A), RV416 (DECK B) so that the fre- quency counter reading becomes 5,980 ± 80 Hz. (Normal speed adjustment) 6. Press the · button to playback. 7. Press the HIGH/NORMAL button to playback at normal speed. 8. Adjust RV317 (DECK A), RV417 (DECK B) so that the fre- quency counter reading becomes 3,000 ± 90 Hz. (Pitch control adjustment) (DECK A) 9. Press the PITCH CONTROL button to set to ON . 10. Set PITCH CONTROL knob to mechanical center. 11. Press the · button to playback. 12. Adjust RV318 so that the frequency counter reading becomes 2,990 ± 90 Hz. Adjustment Location: MAIN board (See page 14.) Sample value of wow and flutter W.RMS (JIS) less than 0.3% . (test tape : WS-48B) Playback Level Adjustment DECK A DECK B Procedure: – Forward Playback Mode – Adjust DECK A : RV111 (L-CH), RV211 (R-CH) and DECK B : RV121 (L-CH), RV221 (R-CH) so the level meter read- ing becomes the adjustment limits below. Adjustment Value: LINE OUT level : –7.7 ± 0.5 dB (0.301 to 0.338 V) Level difference between channels : within 0.5 dB Confirm that the LINE OUT level does not change in playback mode while changing the mode from playback to stop several times. Adjustment Location: MAIN board (See page 14.) set test tape P-4-A100 (10 kHz, –10 dB) level meter LINE OUT 47 kΩ within 1 dB within 1 dB output level R-CH peak R-CH peak L-CH peak L-CH peak screw position screw position V H Screen Pattern set In phase 45˚ 90˚ 135˚ 180˚ good wrong 47 kΩ 47 kΩ L-CH R-CH test tape P-4-A100 (10 kHz, –10 dB) LINE OUT oscilloscope forward side reverse side adjustment screws set frequency counter 47 kΩ LINE OUT test tape WS-48B (3 kHz, 0 dB) set test tape P-4-L300 (315 Hz, 0 dB) level meter LINE OUT 47 kΩ www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 13 – Bias Consumption Current Adjustment DECK A DECK B This adjustment should be performed when replacing the head assy or the bias oscillator transformer (T131, T141),(T231, T241). Setting: REC LEVEL knob : standard recording position (See page 11.) Procedure: 1. Connect the digital voltmeter to test point TP331 ( DECK A) and TP441 (DECK B). 2. Set DECK A: RV131 (L-CH), RV231 (R-CH) and DECK B: RV141 (L-CH), RV241 (R-CH) to mechanical center. 3. Press the · button to playback. 4. Adjust DECK A: T131 (L-CH), T231 (R-CH) and DECK B: T141 (L-CH), T241 (R-CH) so that the digital voltmeter reading becomes minimum. Adjustment Value: Maximum 220 mV Adjustment Location: MAIN board (See page 14.) Record Bias Adjustment DECK A DECK B Setting: REC LEVEL knob : standard record position (See page 11.) Procedure: 1. Set to test mode (See page 11.) 2. Insert a tape into deck B, press the REC r button and then press the · button to start recording. Adjustment level: The palyback output of 10 kHz level difference against 315 Hz ref- erence should be ± 0.5 dB. Adjustment Location: MAIN board (See page 14.) Record Level Adjustment DECK A DECK B Setting: REC LEVEL knob : standard record position (See page 11.) Procedure: 1. Set to test mode (See page 11.) 2. Insert a tspe into deck B, press the REC r button and then press the · button to start recording. 3. Record Mode 4. Playback Mode set AF OSC attenuator 10 kΩ 600 Ω LINE IN 1) 315 Hz 2) 10 kHz 50 mV (–23.8 dB) blank tape CS-123 3. Record Mode set recorded portion level meter LINE OUT 47 kΩ 4. Playback Mode 5. Confirm playback the signal recorded in step 2 become adjust- ment level as follows. If the selevels do not adjustment level, adjust DECK A: RV131 (L-CH), RV231 (R-CH) and DECK B: RV141 (L-CH), RV241 (R-CH) to repeat steps 3 and 4. set AF OSC attenuator 10 kΩ 600 Ω LINE IN blank tape CS-123 315 Hz, 50 mV (–23.8 dB) set recorded portion level meter LINE OUT 47 kΩ 5. Confirm playback the signal recorded in step 2 become adjust- ment level as follows. If the selevels do not adjustment level, adjust the RV101 (L-CH) and RV201 (R-CH) to repeat steps 3 and 4. Adjustment Value: LINE OUT level : –23.8 ± 0.5 dB (47.2 to 53.0 mV) Adjustment Location: MAIN board (See page 14.) set 3 2 1 blank tape CS-413 TP331 (DECK A) TP441 (DECK B) L-CH R-CH digital voltmeter LINE IN no signal www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 14 – Adjustment Location: main board [MAIN board] (Component side) RV111 PB LEVEL DECK A (L) RV211 PB LEVEL DECK A (R) TP331 REC BIAS T231 BIAS CURRENT DECK A (R) BIAS CURRENT DECK A (L) REC BIAS DECK A (L) RV231 REC BIAS DECK A (R) T131 RV131 RV318 PITCH CONTROL (DECK A) RV317 NORMAL SPEED (DECK A) RV316 HIGH SPEED (DECK A) 100 81 80 51 31 1 IC801 50 30 RV102 REC LEVEL DECK A (L) RV202 REC LEVEL DECK A (R) RV417 NORMAL SPEED (DECK B) RV416 HIGH SPEED (DECK B) RV241 REC BIAS DECK B (R) RV141 REC BIAS DECK B (L) RV201 REC LEVEL (R) REC BIAS T241 BIAS CURRENT DECK B (R) BIAS CURRENT DECK B (L) T141 52 33 32 20 64 1 IC551 19 51 RV101 REC LEVEL (L) RV121 PB LEVEL DECK B (L) RV221 PB LEVEL DECK B (R) TP441 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com TC-WE635 WAVEFORMS – MAIN SECTION (3/4) – THIS NOTE IS COMMON FOR PRINTED WIRING BOARDS AND SCHEMATIC DIAGRAMS. (In addition to this, the necessary note is printed in each block.) For schematic diagrams. Note: • All capacitors are in µF unless otherwise noted. pF: µµF 50 WV or less are not indicated except for electrolytics and tantalums. • All resistors are in Ω and 1/4 W or less unless otherwise specified. • % : indicates tolerance. • ¢ : internal component. • 1 : fusible resistor. • C : panel designation. For printed wiring boards. Note: • X : parts extracted from the component side. • b : Pattern from the side which enables seeing. • Transistor of “B” and “C” indication is omitted. • U : B+ Line. • V : B– Line. • H : adjustment for repair. • Voltage is dc with respect to ground under no-signal (detuned) condition. no mark : STOP ( ) : REC < > : PB ∗ : Can not be measured. • Voltages are taken with a VOM (Input impedance 10 MΩ). Voltage variations may be noted due to normal produc- tion tolerances. • Waveforms are taken with a oscilloscope. Voltage variations may be noted due to normal produc- tion tolerances. • Circled numbers refer to waveforms. • Signal path. E : PB a : REC • Abbreviation CND : Canadian model. AUS : Australian model. SP : Singapore model. MY : Malaysia model. CH : Chinese model. • Indication of transistor 1 IC801 #ª EXTAL Note: The components identi- fied by mark ! or dotted line with mark ! are criti- cal for safety. Replace only with part number specified. Note: Les composants identifiés par une marque ! sont critiques pour la sécurité. Ne les remplacer que par une piéce portant le numéro spécifié. SECTION 6 DIAGRAMS 6-1. CIRCUIT BOARDS LOCATION 4.4Vp-p 10MHz TRANS (A) board (4 E) (Except SP,MY) MAIN board RECVOL board (4 G) H.P board (4 D) HEAD RELAY (REC/PB) board (Deck B) HEAD RELAY (REC/PB) board (Deck A) LEAF SW (REC/PB) board (Deck B) PANEL board (4 A) DIRECTION board (4 C) POWER board (4 F) LEAF SW (REC/PB) board (Deck A) TRANS (B) board (4 B) C These are omitted E B – 15 – – 16 – • 4A to 4G are including into the mounted panel board. w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com TC-WE635 – 18 – – 17 – 6-2. PRINTED WIRING BOARD – MAIN SECTION – • See page 15 for Circuit Boards Location. D306 F-10 D307 F-10 D318 F-10 D351 F-11 D451 C-1 D521 E-9 D522 E-9 D601 A-6 D701 B-10 D702 B-10 D703 A-10 D704 A-10 D705 A-10 D706 A-10 • Semiconductor Location Ref. No. Location Ref. No. Location D707 B-10 D708 A-7 D709 A-8 D710 B-8 D711 A-8 D712 A-10 D713 B-11 D714 C-10 D715 C-10 D716 B-11 D801 F-6 IC321 D-12 IC331 G-13 (Page 35) (Page 35) (Page 39) (Page 31) (Page 35) (Page 35) (Page 27) (Page 36) (Page 27) IC421 A-2 IC431 F-2 IC501 D-3 IC502 A-6 IC504 F-7 IC561 D-9 IC701 A-8 IC801 D-7 IC802 E-6 IC803 G-9 IC804 G-8 IC805 G-4 IC806 G-3 Ref. No. Location Ref. No. Location Ref. No. Location Q101 B-3 Q102 A-5 Q103 F-7 Q104 C-5 Q201 C-2 Q202 A-4 Q203 F-7 Q204 E-1 Q301 H-7 Q302 H-7 Q303 H-7 Q306 F-10 Q307 G-10 Q308 F-10 Q311 H-8 Q312 H-8 Q314 H-8 Q316 G-10 Q317 G-10 Q318 G-10 Q341 D-13 Q342 D-13 Q343 D-13 Q351 G-11 Q371 C-10 Q373 C-10 Q401 H-6 Q402 G-6 Q403 G-6 Q411 G-5 Q412 G-6 Q414 G-5 Q417 F-5 Q441 G-2 Q442 H-2 Q443 H-2 Q451 C-1 Q471 C-8 Q473 C-8 Q501 A-5 Q502 E-9 Q503 E-9 Ref. No. Location Q505 G-11 Q506 F-3 Q601 A-5 Q701 A-8 Q702 A-7 Q703 A-9 Q704 A-10 Q707 C-10 Q708 C-11 Q801 F-6 Ref. No. Location w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com TC-WE635 – 19 – – 20 – 6-3. SCHEMATIC DIAGRAM – MAIN (1/4) SECTION – (Page 34) (Page 28) (Page 21) (Page 21) (Page 25) (Page 23) (Page 25) (Page 23) (Page 23) (Page 23) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com TC-WE635 – 21 – – 22 – 6-4. SCHEMATIC DIAGRAM – MAIN (2/4) SECTION – (Page 19) (Page 19) (Page 23) (Page 23) (Page 25) (Page 25) (Page 25) (Page 25) (Page 24) (Page 34) (Page 28) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com TC-WE635 – 23 – – 24 – 6-5. SCHEMATIC DIAGRAM – MAIN (3/4) SECTION – • See page 16 for Waveforms. • See page 17 for Printed Wiring Board. • See page 41 for IC Pin Functions. (Page 33) (Page 34) (Page 30) (Page 20) (Page 20) (Page 20) (Page 20) (Page 22) (Page 22) (Page 25) (Page 25) (Page 26) (Page 22) (Page 26) (Page 37) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com TC-WE635 – 25 – – 26 – 6-6. SCHEMATIC DIAGRAM – MAIN (4/4) SECTION – (Page 23) (Page 20) (Page 23, 24) (Page 24) (Page 24) (Page 34) (Page 22) (Page 20) (Page 22) (Page 22) (Page 22) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com TC-WE635 – 27 – – 28 – 6-7. PRINTED WIRING BOARD – DECK SECTION – • See page 15 for Circuit Boards Location. 6-8. SCHEMATIC DIAGRAM – DECK SECTION – 09 (Page 17, 18) 09 (Page 19) (Page 21) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com TC-WE635 – 29 – – 30 – 6-9. SCHEMATIC DIAGRAM – DISPLAY SECTION – (Page 23, 24) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com TC-WE635 – 31 – – 32 – 6-10. PRINTED WIRING BOARD – DISPLAY SECTION – • See page 15 for Circuit Boards Location. (Page 18) D904 B-3 D905 B-2 D906 B-2 D906 B-2 D907 B-2 D908 B-2 IC901 B-5 IC902 A-2 Q901 A-2 • Semiconductor Location Ref. No. Location w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com TC-WE635 – 33 – – 34 – 6-11. SCHEMATIC DIAGRAM – PANEL SECTION – (Page 23) (Page 23) (Page 19) (Page 21) (Page 26) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com TC-WE635 – 35 – – 36 – 6-12. PRINTED WIRING BOARD – PANEL SECTION – • See page 15 for Circuit Boards Location. (Page 18) (Page 17) (Page 18) 09 (Page 18) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com TC-WE635 – 37 – – 38 – 6-13. SCHEMATIC DIAGRAM – POWER SECTION – (Page 24) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com TC-WE635 – 39 – – 40 – 6-14. PRINTED WIRING BOARD – POWER SECTION – • See page 15 for Circuit Boards Location. (Page 18) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com TC-WE635 – 41 – – 42 – Pin No. Pin Name I/O Function 49 CD SYNC LED O SYNCHRO LED driver “L”: ON 50 CAP, M2 (B) O 51 CAP, M4 (B) O 52 CAP, M3 (B) O 53 CAP, M1 (B) O 54 BIAS CAL 0 (B) O BIAS CAL control 0 (DECK B) 55 BIAS CAL 1 (B) O BIAS CAL control 1 (DECK B) 56 BIAS CAL 2 (B) O BIAS CAL control 2 (DECK B) 57 BIAS CAL 3 (B) O BIAS CAL control 3 (DECK B) 58 CAP, M2 (A) O 59 CAP, M1 (A) O 60 CAP, M3 (A) O 61 CAP, M4 (A) O 62 BIAS CAL 0 (A) O BIAS CAL control 0 (DECK A) 63 BIAS CAL 1 (A) O BIAS CAL control 1 (DECK A) 64 BIAS CAL 2 (A) O BIAS CAL control 2 (DECK A) 65 BIAS CAL 3 (A) O BIAS CAL control 3 (DECK A) 66 NC – Not used 67 CAP, M H/L O Capstan motor high/normal selector output “L”: ON 68 PITCH ON/OFF O Pitch control ON/OFF output 69 OSC ON/OFF O CAL detection ON/OFF select output 70 OSC H/L O CAL oscillator ON/OFF select output 71 LINE MUTE O Line mute ON/OFF control output 72 to 87 NC – Not used 88 VF – Ground 89 VDD – Power supply (+5V) 90 N.C – Not used 91 VSS – Ground 92 BIAS (A) O Bias ON/OFF output (DECK A) 93 BIAS (B) O Bias ON/OFF output (DECK B) 94 PITCH CON-SW O Pitch control ON/OFF control output “L”: ON 95 AMS IN I AMS amp selector 96 TRG (B) O Trigger control output (DECK B) 97 TRG (A) O Trigger control output (DECK A) 98 NC – Not used 99 PLAYSW (A) I Play swich input (DECK A) 100 70U (A) I 70µ output (DECK A) Capstan motor driver (DECK B) Capstan motor driver (DECK A) 6-15. IC PIN FUNCTION • IC801 SYSTEM CONTROL (CXP82432A-007Q) (MAIN board) Pin No. Pin Name I/O Function 1 PLAYSW (B) I Play switch input (DECK B) 2 70U (B) O 70µ output (DECK B) 3 METAL (B) I METAL input (DECK B) 4 SIRCS IN I Sircs signal input 5 POWER IN I Power hold input 6 VOL OUT O Volume output 7 A/B SEL I Playback A/B selector input “L” : A, “H” : B 8 CONTROL-A IN I Control A signal input 9 CONTROL-A OUT O Control A signal output 10 FL CLK I FL CLK control input 11 FL DATA IN I Display control input 12 FL DATA OUT O Display control output 13 CS I Sircs signal input 14 REC MUTE A O Recording mute output “L” : Mute ON 15 REC /PB O Record /playback dolby NR mode selector output “L” : Playback 16 REC CAL 0 (B) O Recoding CAL control 0 (DECK B) 17 REC CAL 1 (B) O Recoding CAL control 1 (DECK B) 18 GP CAL 0 (B) O GP CAL control 0 (DECK B) 19 GP CAL 1 (B) O GP CAL control 1 (DECK B) 20 REC CAL 0 (A) O Recoding CAL control 0 (DECK A) 21 REC CAL 1 (A) O Recoding CAL control 1 (DECK A) 22 GP CAL 0 (A) O GP CAL control 0 (DECK A) 23 GP CAL 1 (A) O GP CAL control 1 (DECK A) 23 NC – Not used 24 REC MUTE B O Recording mute output (DECK B) 25 CAL/OFF/S O CAL select switch 26 C/B/OFF O Dolby selector “H ”: C,“Open”: B, “L”: Dolby off 27 REC EQ H/N O REC EQ high/normal selector output “L”: Dolby 28 PASS/MUTE/DOLBY O Audio selector “H”: Pass , “Open”: Mute,“L”: Recording 29 BS/AMS/OFF O AMS amp selector “H”: BS, “Open”: AMS, “L”: OFF 30 RELAY (B) I Relay swich input (DECK B) 31 RELAY (A) I Relay swich input (DECK A) 32 METER (L) I Meter L-CH input 33 METER (R) I Meter R-CH input 34 HALF (B) I Half swich input (DECK B) 35 SHUT (B) I Capstan motor rotation detection input (DECK B) 36 SHUT (A) I Capstan motor rotation detection input (DECK A) 37 HALF (A) I Half swich input (DECK A) 38 RESET I System reset input 39 EXTAL O System clock oscillator output (10 MHz) 40 XTAL I System clock oscillator input (10 MHz) 41 VSS – 42 TX – Ground 43 TEX – 44 VOL IN I Auto rec level control input 45 DIR MODE IN I Key input 46 AVREF – Connected to power supply 47 AV SS – Ground 48 AR LED O AUTO LED driver “H”: ON w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 43 – SECTION 7 EXPLODED VIEWS 7-1. CASE SECTION NOTE: • Items marked “*” are not stocked since they are seldom required for routine service. Some delay should be anticipated when ordering these items. • The mechanical parts with no reference number in the exploded views are not supplied. • Hardware (# mark) list and accessories and pack- ing materials are given in the last of this parts list. • Abbreviation CND : Canadian model SP : Singapore model MY : Malaysia model AUS : Australian model CH : Chinese model Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark * 1 3-032-412-01 PANEL, BACK (US) * 1 3-032-412-11 PANEL, BACK (CND) * 1 3-032-412-21 PANEL, BACK (AEP) * 1 3-032-412-31 PANEL, BACK (UK) * 1 3-032-412-41 PANEL, BACK (AUS) * 1 3-032-412-51 PANEL, BACK (SP,MY) * 1 3-032-412-61 PANEL, BACK (CH) * 2 3-935-634-01 CASE (410726) 3 3-703-244-00 BUSHING (2104), CORD (EXCEPT US,CND)) * 3 3-703-571-11 BUSHING (S)(4516), CORD (CND) 3 4-966-267-11 BUSHING (FBS001), CORD (US) 4 3-363-099-01 SCREW (CASE 3 TP2) !S902 1-692-155-11 SELECTOR, POWER VOLTAGE (SP,MY) 4 2 4 3 1 S902 SP,MY not supplied #1 #1 #1 #1 #1 #1 (SP,MY) #2 The components identified by mark ! or dotted line with mark ! are critical for safety. Replace only with part number specified. Les composants identifiés par une marque ! sont critiques pour la sécurité. Ne les remplacer que par une piéce portant le numéro spécifié. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 44 – 7-2. CHASSIS SECTION Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark * 54 4-978-398-21 CUSHION * 55 3-346-265-31 HOLDER, PC BOARD * 56 A-2007-811-A MAIN BOARD, COMPLETE 57 4-977-591-01 FOOT (F50150S)(EXCEPT US,CND) 57 4-977-591-11 FOOT (F50150S)(US,CND) !T901 1-431-786-12 TRANSFORMER, POWER (AEP,UK,AUS,CH) !T901 1-431-789-12 TRANSFORMER, POWER (SP,MY) !T901 1-431-788-12 TRANSFORMER, POWER (US,CND) 51 1-751-086-11 WIRE (FLAT TYPE)(13 CORE)(180mm) 52 1-769-976-11 WIRE (FLAT TYPE)(13 CORE)(140mm) !53 1-558-945-21 CORD, POWER (POLAR.SPT-1)(CND) !53 1-575-651-21 CORD, POWER (SP,MY) !53 1-751-535-11 CORD, POWER (UK) !53 1-777-107-11 CORD, POWER (AEP) !53 1-777-218-11 CORD, POWER (AUS) !53 1-783-108-11 CORD, POWER (CH) !53 1-783-531-51 CORD, POWER (US) #1 #1 #1 #1 #1 US, CND AEP, SP, MY CH UK AUS #2 #2 #2 T901 4 B not supplied not supplied 51 52 57 54 54 57 53 53 53 53 53 55 55 56 4 E (Except SP,MY) The components identified by mark ! or dotted line with mark ! are critical for safety. Replace only with part number specified. Les composants identifiés par une marque ! sont critiques pour la sécurité. Ne les remplacer que par une piéce portant le numéro spécifié. 4 B and 4 E are including into the mounted panel board (Ref. No.163). 4 B TRANS (B) board 4 E TRANS (A) board (EXCEPT SP, MY) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 45 – 7-3. CASSETTE HOLDER SECTION Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 101 X-3377-097-1 LID (A) ASSY, CASSETTE 102 X-3376-716-1 LID (B) ASSY, CASSETTE 103 3-931-427-31 BUTTON (EJ) 104 3-022-410-01 DAMPER 105 3-019-450-01 PLATE (L), FULCRUM 106 X-3375-103-1 HOLDER (R) ASSY, CASSETTE 107 3-019-455-01 SPRING (R), LOADING 108 3-019-451-01 PLATE (R), FULCRUM 109 X-3375-107-1 HOLDER (L) ASSY, CASSETTE 110 3-019-454-01 SPRING (L), LOADING 111 3-019-453-01 LEVER (LOCK R) 112 3-019-456-01 SCREW, STEP 113 3-019-452-01 LEVER (LOCK L) 114 4-951-620-01 SCREW (2.6X8), +BVTP 101 102 103 103 110 109 108 104 114 105 114 114 112 111 114 108 113 112 107 106 105 104 114 TCM-230ASR4 TCM-230HSR4 #4 #4 #3 #3 #3 #3 TCM-230ASR4 TCM-230HSR4 114 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 46 – 7-4. FRONT PANEL SECTION Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 159 3-931-429-41 BUTTON (POWER) 160 3-380-952-21 BUTTON 161 3-931-378-01 KNOB (F10) 162 1-769-950-11 WIRE (FLAT TYPE)(11 CORE) * 163 A-2007-812-A PANEL BOARD, COMPLETE (EXCEPT SP,MY) * 163 A-2007-816-A PANEL BOARD, COMPLETE (SP,MY) * 164 3-377-337-11 HOLDER (FL) 165 4-951-620-01 SCREW (2.6X8), +BVTP FLT901 1-517-263-11 INDICATOR TUBE, FLUORESCENT 151 X-3376-711-1 PANEL ASSY, FRONT (EXCEPT US,CND) 151 X-3376-762-1 PANEL ASSY, FRONT (US,CND) 152 3-021-239-01 KNOB (REC) 153 4-996-698-41 EMBLEM, SONY 154 4-977-593-01 RING (DIA. 50), ORNAMENTAL (EXCEPT US,CND) * 155 4-978-398-21 CUSHION 156 3-021-232-01 BUTTON (COUNTER) 157 3-021-230-01 BUTTON (FUNCTION) 158 3-931-241-21 BUTTON (SYNCHRO) #5 FLT901 Except US,CND 152 155 154 153 151 158 156 157 165 165 165 163 (Including 4 A to 4 G) 165 162 165 165 161 160 165 159 164 4 A 4 D (Except SP,MY) 4 G 4 F 4 C 4 A to 4 G are including into the mounted panel board (Ref. No.163). 4 A PANEL board 4 C DIRECTION board 4 D H.P board 4 F POWER board 4 G RECVOL board www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 47 – 7-5. TAPE MECHANISM SECTION (TCM-230ASR4/HSR4) Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 216 3-016-575-11 SPRING, TORSION 217 X-3376-933-1 FLYWHEEL (REV) ASSY 218 3-024-405-01 BELT (FR2) 219 X-3376-932-1 FLYWHEEL (FWD) ASSY 220 3-016-570-01 BELT (CAPSTAN) * 221 1-668-635-11 HEAD RELAY (REC/PB) BOARD (DECK A/B) 222 3-036-914-01 RIVET, PUSH 223 3-030-823-01 SCREW (+BVTT)(2X3.5) HRPE1 A-2004-646-C DECK ASSY, HEAD (RECORD/PLAYBACK/ERASE) (DECK A) HRPE2 A-2004-646-C DECK ASSY, HEAD (RECORD/PLAYBACK/ERASE) (DECK B) M1001 A-2004-644-A MOTOR ASSY, CAPSTAN (DECK A) M1002 A-2004-644-A MOTOR ASSY, CAPSTAN (DECK B) 201 3-016-574-11 SPRING (HEAD), TENSION 202 X-3374-156-1 PINCH LEVER (REV) ASSY * 203 1-668-628-11 LEAF SW (REC/PB) BOARD (DECK A/B) 204 3-032-809-02 SPRING (L), TORSION (DECK B) 205 3-016-572-01 LEVER (EJECT PREVENTION L)(DECK B) 206 3-016-565-01 BASE (PINCH LEVER REV) 207 3-016-567-01 SPRING (CASSETTE), LEAF 208 3-032-810-02 SPRING (R), TORSION (DECK A) 209 3-016-573-01 LEVER (EJECT PREVENTION R)(DECK A) 210 X-3374-155-1 PINCH LEVER (FWD) ASSY 211 3-016-564-01 BASE (PINCH LEVER FWD) 212 3-019-208-01 WASHER, STOPPER * 213 X-3374-828-1 CHASSIS ASSY, MECHANICAL 214 A-2004-699-A MECHANICAL BLOCK ASSY 215 3-016-566-01 SLIDER, REVERSE 210 208 209 211 215 213 216 217 221 212 218 219 220 222 201 202 204 205 206 207 214 203 223 M1001 (Deck A) M1002 (Deck B) #9 #6 #7 #8 HRPE1 (Deck A) HRPE2 (Deck B) Deck B Deck A www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 48 – SECTION 8 ELECTRICAL PARTS LIST Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark HEAD RELAY (REC/PB) • SEMICONDUCTORS In each case, u: µ , for example: uA...: µ A..., uPA...: µ PA..., uPB...: µ PB..., uPC...: µ PC..., uPD...: µ PD... • CAPACITORS uF : µ F • COILS uH : µ H • Abbreviation CND : Canadian model SP : Singapore model MY : Malaysia model AUS : Australian model CH : Chinese model • Due to standardization, replacements in the parts list may be different from the parts specified in the diagrams or the components used on the set. • -XX, -X mean standardized parts, so they may have some difference from the original one. • Items marked “*” are not stocked since they are seldom required for routine service. Some delay should be anticipated when ordering these items. • RESISTORS All resistors are in ohms METAL: Metal-film resistor METAL OXIDE: Metal Oxide-film resistor F : nonflammable Note: When indicating parts by reference number, please include the board name. LEAF SW (REC/PB) MAIN * 1-668-635-11 HEAD RELAY (REC/PB) BOARD ************************* < CONNECTOR > CN1003 1-564-722-11 PIN, CONNECTOR (SMALL TYPE) 6P ************************************************************** * 1-668-628-11 LEAF SWITCH (REC/PB) BOARD ************************* CN1001 1-568-444-11 SOCKET, CONNECTOR 13P < DIODE > D1001 8-719-991-33 DIODE 1SS133T-77 < IC > IC1002 8-749-014-38 IC PHOTO INTERRUPTER SG-264 < RESISTOR > R1002 1-249-409-11 CARBON 220 5% 1/4W F R1003 1-249-414-11 CARBON 560 5% 1/4W F R1004 1-247-834-11 CARBON 1.3K 5% 1/4W R1005 1-247-818-91 CARBON 300 5% 1/4W < SWITCH > S1002 1-570-953-11 SWITCH, PUSH (1 KEY)(PLAY SW) S1005 1-771-205-11 SWITCH, LEAF (REC PROOF (SIDE A)) S1006 1-771-333-11 SWITCH, LEAF (HALF DET) S1007 1-771-205-11 SWITCH, LEAF (METAL DET) S1008 1-771-205-11 SWITCH, LEAF (CrO2 DET) S1009 1-771-205-11 SWITCH, LEAF (REC PROOF (SIDE B)) ************************************************************** * A-2007-811-A MAIN BOARD, COMPLETE ********************* < CAPACITOR > C101 1-162-284-31 CERAMIC 150PF 10% 50V C102 1-126-961-11 ELECT 2.2uF 20% 50V C103 1-162-600-11 CERAMIC 0.0047uF 30% 16V C104 1-126-963-11 ELECT 4.7uF 20% 50V C105 1-162-302-11 CERAMIC 0.0022uF 20% 16V C106 1-126-963-11 ELECT 4.7uF 20% 50V C107 1-126-964-11 ELECT 10uF 20% 50V C108 1-130-495-00 MYLAR 0.1uF 5% 50V C109 1-137-375-11 FILM 0.068uF 5% 50V C110 1-126-964-11 ELECT 10uF 20% 50V C111 1-126-959-11 ELECT 0.47uF 20% 50V C112 1-126-963-11 ELECT 4.7uF 20% 50V C113 1-126-963-11 ELECT 4.7uF 20% 50V C114 1-126-961-11 ELECT 2.2uF 20% 50V C115 1-137-436-11 FILM 0.0039uF 5% 50V C116 1-126-959-11 ELECT 0.47uF 20% 50V C117 1-126-963-11 ELECT 4.7uF 20% 50V C120 1-162-289-31 CERAMIC 390PF 10% 50V C121 1-162-294-31 CERAMIC 0.001uF 10% 50V C122 1-162-282-31 CERAMIC 100PF 10% 50V C123 1-137-372-11 FILM 0.022uF 5% 50V C124 1-126-963-11 ELECT 4.7uF 20% 50V C125 1-162-289-31 CERAMIC 390PF 10% 50V C126 1-162-282-31 CERAMIC 100PF 10% 50V C127 1-137-372-11 FILM 0.022uF 5% 50V C128 1-126-963-11 ELECT 4.7uF 20% 50V C131 1-162-288-31 CERAMIC 330PF 10% 50V C132 1-107-609-11 CERAMIC 75PF 5% 500V C133 1-137-433-11 FILM 0.0012uF 5% 50V C134 1-102-973-00 CERAMIC 100PF 5% 50V C135 1-136-356-11 FILM 470PF 5% 100V C136 1-137-374-11 FILM 0.047uF 5% 50V C137 1-161-494-00 CERAMIC 0.022uF 25V C138 1-162-306-11 CERAMIC 0.01uF 20% 16V C141 1-162-288-31 CERAMIC 330PF 10% 50V C142 1-107-609-11 CERAMIC 75PF 5% 500V C143 1-137-433-11 FILM 0.0012uF 5% 50V C144 1-102-973-00 CERAMIC 100PF 5% 50V C145 1-136-356-11 FILM 470PF 5% 100V C146 1-137-374-11 FILM 0.047uF 5% 50V C147 1-161-494-00 CERAMIC 0.022uF 25V C148 1-162-306-11 CERAMIC 0.01uF 20% 16V C201 1-162-284-31 CERAMIC 150PF 10% 50V C202 1-126-961-11 ELECT 2.2uF 20% 50V C203 1-162-600-11 CERAMIC 0.0047uF 30% 16V C204 1-126-963-11 ELECT 4.7uF 20% 50V C205 1-162-302-11 CERAMIC 0.0022uF 20% 16V C206 1-126-963-11 ELECT 4.7uF 20% 50V C207 1-126-964-11 ELECT 10uF 20% 50V The components identified by mark ! or dotted line with mark ! are critical for safety. Replace only with part number specified. Les composants identifiés par une marque ! sont critiques pour la sécurité. Ne les remplacer que par une piéce portant le numéro spécifié. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 49 – Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark MAIN C208 1-130-495-00 MYLAR 0.1uF 5% 50V C209 1-137-375-11 FILM 0.068uF 5% 50V C210 1-126-964-11 ELECT 10uF 20% 50V C211 1-126-959-11 ELECT 0.47uF 20% 50V C212 1-126-963-11 ELECT 4.7uF 20% 50V C213 1-126-963-11 ELECT 4.7uF 20% 50V C214 1-126-961-11 ELECT 2.2uF 20% 50V C215 1-137-436-11 FILM 0.0039uF 5% 50V C216 1-126-959-11 ELECT 0.47uF 20% 50V C217 1-126-963-11 ELECT 4.7uF 20% 50V C220 1-162-289-31 CERAMIC 390PF 10% 50V C221 1-162-294-31 CERAMIC 0.001uF 10% 50V C222 1-162-282-31 CERAMIC 100PF 10% 50V C223 1-137-372-11 FILM 0.022uF 5% 50V C224 1-126-963-11 ELECT 4.7uF 20% 50V C225 1-162-289-31 CERAMIC 390PF 10% 50V C226 1-162-282-31 CERAMIC 100PF 10% 50V C227 1-137-372-11 FILM 0.022uF 5% 50V C228 1-126-963-11 ELECT 4.7uF 20% 50V C231 1-162-288-31 CERAMIC 330PF 10% 50V C232 1-107-609-11 CERAMIC 75PF 5% 500V C233 1-137-433-11 FILM 0.0012uF 5% 50V C234 1-102-973-00 CERAMIC 100PF 5% 50V C235 1-136-356-11 FILM 470PF 5% 100V C236 1-137-374-11 FILM 0.047uF 5% 50V C237 1-161-494-00 CERAMIC 0.022uF 25V C238 1-162-306-11 CERAMIC 0.01uF 20% 16V C241 1-162-288-31 CERAMIC 330PF 10% 50V C242 1-107-609-11 CERAMIC 75PF 5% 500V C243 1-137-433-11 FILM 0.0012uF 5% 50V C244 1-102-973-00 CERAMIC 100PF 5% 50V C245 1-136-356-11 FILM 470PF 5% 100V C246 1-137-374-11 FILM 0.047uF 5% 50V C247 1-161-494-00 CERAMIC 0.022uF 25V C248 1-162-306-11 CERAMIC 0.01uF 20% 16V C321 1-104-664-11 ELECT 47uF 20% 25V C322 1-104-664-11 ELECT 47uF 20% 25V C331 1-104-664-11 ELECT 47uF 20% 16V C332 1-107-584-11 CERAMIC 4PF 0.25PF 500V C333 1-126-965-11 ELECT 22uF 20% 50V C334 1-126-959-11 ELECT 0.47uF 20% 50V C341 1-136-293-11 FILM 0.0082uF 5% 100V C342 1-136-173-00 FILM 0.47uF 5% 50V C343 1-130-299-00 FILM 0.012uF 5% 50V C344 1-137-436-11 FILM 0.0039uF 5% 50V C345 1-137-436-11 FILM 0.0039uF 5% 50V C346 1-126-964-11 ELECT 10uF 20% 50V C351 1-126-964-11 ELECT 10uF 20% 50V C417 1-126-959-11 ELECT 0.47uF 20% 50V C421 1-104-664-11 ELECT 47uF 20% 25V C422 1-104-664-11 ELECT 47uF 20% 25V C431 1-104-664-11 ELECT 47uF 20% 16V C432 1-107-584-11 CERAMIC 4PF 0.25PF 500V C433 1-126-965-11 ELECT 22uF 20% 50V C434 1-126-959-11 ELECT 0.47uF 20% 50V C441 1-136-293-11 FILM 0.0082uF 5% 100V C442 1-136-173-00 FILM 0.47uF 5% 50V C443 1-130-299-00 FILM 0.012uF 5% 50V C444 1-137-436-11 FILM 0.0039uF 5% 50V C445 1-137-436-11 FILM 0.0039uF 5% 50V C446 1-126-964-11 ELECT 10uF 20% 50V C451 1-126-964-11 ELECT 10uF 20% 50V C501 1-126-964-11 ELECT 10uF 20% 50V C502 1-126-964-11 ELECT 10uF 20% 50V C503 1-126-964-11 ELECT 10uF 20% 50V C505 1-126-960-11 ELECT 1uF 20% 50V C506 1-130-497-00 MYLAR 0.15uF 5% 50V C507 1-136-173-00 FILM 0.47uF 5% 50V C508 1-126-959-11 ELECT 0.47uF 20% 50V C509 1-126-965-11 ELECT 22uF 20% 50V C510 1-126-960-11 ELECT 1uF 20% 50V C511 1-126-916-11 ELECT 1000uF 20% 6.3V C521 1-137-457-11 FILM 0.0027uF 5% 50V C522 1-130-494-11 MYLAR 0.082uF 5% 50V C523 1-137-374-11 FILM 0.047uF 5% 50V C524 1-137-366-11 FILM 0.0022uF 5% 50V C530 1-126-965-11 ELECT 22uF 20% 50V C561 1-136-168-00 FILM 0.18uF 5% 50V C562 1-137-370-11 FILM 0.01uF 5% 50V C563 1-136-175-00 FILM 0.68uF 5% 50V C601 1-164-159-11 CERAMIC 0.1uF 50V C701 1-128-547-11 ELECT 6800uF 20% 16V C702 1-126-937-11 ELECT 4700uF 20% 16V C703 1-126-960-11 ELECT 1uF 20% 50V C704 1-126-969-11 ELECT 220uF 20% 50V C705 1-126-963-11 ELECT 4.7uF 20% 50V C706 1-126-926-11 ELECT 1000uF 20% 10V C707 1-126-926-11 ELECT 1000uF 20% 10V C708 1-126-963-11 ELECT 4.7uF 20% 50V C710 1-126-935-11 ELECT 470uF 20% 6.3V C711 1-126-947-11 ELECT 47uF 20% 35V C801 1-104-665-11 ELECT 100uF 20% 10V C802 1-161-494-00 CERAMIC 0.022uF 25V C803 1-126-959-11 ELECT 0.47uF 20% 50V C810 1-161-494-00 CERAMIC 0.022uF 25V C811 1-164-159-11 CERAMIC 0.1uF 50V C830 1-161-494-00 CERAMIC 0.022uF 25V C831 1-161-494-00 CERAMIC 0.022uF 25V C834 1-161-494-00 CERAMIC 0.022uF 25V C836 1-161-494-00 CERAMIC 0.022uF 25V < CONNECTOR > CN301 1-691-770-11 PLUG (MICRO CONNECTOR) 8P CN311 1-784-774-11 CONNECTOR, FFC 13P CN401 1-691-770-11 PLUG (MICRO CONNECTOR) 8P CN411 1-784-774-11 CONNECTOR, FFC 13P * CN803 1-568-934-11 PIN, CONNECTOR 7P * CN807 1-568-954-11 PIN, CONNECTOR 5P CNA806 1-506-468-11 PIN, CONNECTOR 3P CNM701 1-691-769-11 PLUG (MICRO CONNECTOR) 7P CNS802 1-568-830-11 CONNECTOR, FFC 11P www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 50 – Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark MAIN < DIODE > D306 8-719-911-19 DIODE 1SS119-25 D307 8-719-911-19 DIODE 1SS119-25 D318 8-719-911-19 DIODE 1SS119-25 D351 8-719-911-19 DIODE 1SS119-25 D451 8-719-911-19 DIODE 1SS119-25 D521 8-719-911-19 DIODE 1SS119-25 D522 8-719-911-19 DIODE 1SS119-25 D601 8-719-911-19 DIODE 1SS119-25 D701 8-719-024-99 DIODE 11ES2-NTA2B D702 8-719-024-99 DIODE 11ES2-NTA2B D703 8-719-024-99 DIODE 11ES2-NTA2B D704 8-719-024-99 DIODE 11ES2-NTA2B D705 8-719-911-19 DIODE 1SS119-25 D706 8-719-911-19 DIODE 1SS119-25 D707 8-719-024-99 DIODE 11ES2-NTA2B D708 8-719-911-19 DIODE 1SS119-25 D709 8-719-933-33 DIODE HZS6A1L D710 8-719-933-35 DIODE HZS6A3L D711 8-719-933-33 DIODE HZS6A1L D712 8-719-933-35 DIODE HZS6A3L D713 8-719-911-19 DIODE 1SS119-25 D714 8-719-911-19 DIODE 1SS119-25 D715 8-719-911-19 DIODE 1SS119-25 D716 8-719-985-95 DIODE HZS7A2LTA D801 8-719-911-19 DIODE 1SS119-25 < IC > IC321 8-759-710-59 IC NJM4580D-D IC331 8-759-106-56 IC UPC1297CA IC421 8-759-710-59 IC NJM4580D-D IC431 8-759-106-56 IC UPC1297CA IC501 8-752-075-27 IC CXA1878Q IC502 8-759-634-50 IC M5218AL IC504 8-752-070-67 IC CXA1597P IC561 8-759-634-50 IC M5218AL IC701 8-759-634-51 IC M5218AP IC801 8-752-902-28 IC CXP82432A-007Q IC802 8-759-165-82 IC PST600E-T IC803 8-759-916-14 IC SN74HC04AN IC804 8-759-000-48 IC MC14052BCP IC805 8-759-916-14 IC SN74HC04AN IC806 8-759-000-48 IC MC14052BCP < JACK > J501 1-770-614-11 JACK, PIN 4P (LINE IN/OUT) * J601 1-764-188-11 JACK (SMALL TYPE) (DIA. 3.5) (S-LINK CONTROL A1) * J602 1-764-188-11 JACK (SMALL TYPE) (DIA. 3.5) (S-LINK CONTROL A1) < COIL > L131 1-410-780-11 INDUCTOR 27mH L141 1-410-780-11 INDUCTOR 27mH L231 1-410-780-11 INDUCTOR 27mH L241 1-410-780-11 INDUCTOR 27mH < FILTER > LPF101 1-233-271-11 FILTER, LOW PASS LPF201 1-233-271-11 FILTER, LOW PASS < TRANSISTOR > Q101 8-729-029-94 TRANSISTOR DTC143TSA Q102 8-729-142-25 TRANSISTOR 2SD1020-HFE Q103 8-729-030-02 TRANSISTOR DTC144ESA Q104 8-729-030-02 TRANSISTOR DTC144ESA Q201 8-729-029-94 TRANSISTOR DTC143TSA Q202 8-729-142-25 TRANSISTOR 2SD1020-HFE Q203 8-729-030-02 TRANSISTOR DTC144ESA Q204 8-729-030-02 TRANSISTOR DTC144ESA Q301 8-729-801-84 TRANSISTOR 2SB1013-4 Q302 8-729-801-93 TRANSISTOR 2SD1387 Q303 8-729-030-02 TRANSISTOR DTC144ESA Q306 8-729-030-02 TRANSISTOR DTC144ESA Q307 8-729-030-02 TRANSISTOR DTC144ESA Q308 8-729-030-02 TRANSISTOR DTC144ESA Q311 8-729-801-84 TRANSISTOR 2SB1013-4 Q312 8-729-801-93 TRANSISTOR 2SD1387 Q314 8-729-030-02 TRANSISTOR DTC144ESA Q316 8-729-029-56 TRANSISTOR DTA144ESA Q317 8-729-029-56 TRANSISTOR DTA144ESA Q318 8-729-029-56 TRANSISTOR DTA144ESA Q341 8-729-119-76 TRANSISTOR 2SA1175-HFE Q342 8-729-194-57 TRANSISTOR 2SC945-P Q343 8-729-194-57 TRANSISTOR 2SC945-P Q351 8-729-119-76 TRANSISTOR 2SA1175-HFE Q371 8-729-140-04 TRANSISTOR 2SB1116A-L Q373 8-729-030-02 TRANSISTOR DTC144ESA Q401 8-729-801-84 TRANSISTOR 2SB1013-4 Q402 8-729-801-93 TRANSISTOR 2SD1387 Q403 8-729-030-02 TRANSISTOR DTC144ESA Q411 8-729-801-84 TRANSISTOR 2SB1013-4 Q412 8-729-801-93 TRANSISTOR 2SD1387 Q414 8-729-030-02 TRANSISTOR DTC144ESA Q417 8-729-029-56 TRANSISTOR DTA144ESA Q441 8-729-119-76 TRANSISTOR 2SA1175-HFE Q442 8-729-194-57 TRANSISTOR 2SC945-P Q443 8-729-194-57 TRANSISTOR 2SC945-P Q451 8-729-119-76 TRANSISTOR 2SA1175-HFE Q471 8-729-140-04 TRANSISTOR 2SB1116A-L Q473 8-729-030-02 TRANSISTOR DTC144ESA Q501 8-729-119-76 TRANSISTOR 2SA1175-HFE Q502 8-729-620-05 TRANSISTOR 2SC2603-EF Q503 8-729-620-05 TRANSISTOR 2SC2603-EF Q505 8-729-029-94 TRANSISTOR DTC143TSA Q506 8-729-029-94 TRANSISTOR DTC143TSA Q601 8-729-620-05 TRANSISTOR 2SC2603-EF Q701 8-729-141-83 TRANSISTOR 2SB1094-LK Q702 8-729-209-15 TRANSISTOR 2SD2012 Q703 8-729-141-83 TRANSISTOR 2SB1094-LK Q704 8-729-620-05 TRANSISTOR 2SC2603-EF Q707 8-729-119-76 TRANSISTOR 2SA1175-HFE Q708 8-729-140-04 TRANSISTOR 2SB1116A-L www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 51 – Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark Les composants identifiés par une marque ! sont critiques pour la sécurité. Ne les remplacer que par une piéce portant le numéro spécifié. The components identified by mark ! or dotted line with mark ! are critical for safety. Replace only with part number specified. MAIN Q801 8-729-029-66 TRANSISTOR DTC114ESA < RESISTOR > R101 1-249-429-11 CARBON 10K 5% 1/4W R102 1-247-887-00 CARBON 220K 5% 1/4W R103 1-249-441-11 CARBON 100K 5% 1/4W R104 1-249-420-11 CARBON 1.8K 5% 1/4W F R105 1-247-843-11 CARBON 3.3K 5% 1/4W R106 1-247-842-11 CARBON 3K 5% 1/4W R107 1-249-417-11 CARBON 1K 5% 1/4W F R108 1-249-427-11 CARBON 6.8K 5% 1/4W F R109 1-249-429-11 CARBON 10K 5% 1/4W R110 1-249-425-11 CARBON 4.7K 5% 1/4W F R111 1-247-881-00 CARBON 120K 5% 1/4W R112 1-247-807-31 CARBON 100 5% 1/4W R113 1-247-882-11 CARBON 130K 5% 1/4W R114 1-247-850-11 CARBON 6.2K 5% 1/4W R115 1-249-433-11 CARBON 22K 5% 1/4W R116 1-247-843-11 CARBON 3.3K 5% 1/4W R117 1-249-429-11 CARBON 10K 5% 1/4W R118 1-249-409-11 CARBON 220 5% 1/4W F R119 1-249-417-11 CARBON 1K 5% 1/4W F R120 1-249-439-11 CARBON 68K 5% 1/4W R121 1-247-881-00 CARBON 120K 5% 1/4W R122 1-247-807-31 CARBON 100 5% 1/4W R123 1-247-882-11 CARBON 130K 5% 1/4W R124 1-247-850-11 CARBON 6.2K 5% 1/4W R125 1-249-440-11 CARBON 82K 5% 1/4W R126 1-249-421-11 CARBON 2.2K 5% 1/4W F R127 1-249-430-11 CARBON 12K 5% 1/4W R128 1-249-417-11 CARBON 1K 5% 1/4W F R129 1-249-421-11 CARBON 2.2K 5% 1/4W F R130 1-249-434-11 CARBON 27K 5% 1/4W R131 1-249-430-11 CARBON 12K 5% 1/4W R132 1-247-883-00 CARBON 150K 5% 1/4W !R133 1-219-153-11 FUSIBLE 10 5% 1/4W F R134 1-249-435-11 CARBON 33K 5% 1/4W R135 1-249-431-11 CARBON 15K 5% 1/4W R141 1-249-430-11 CARBON 12K 5% 1/4W R142 1-247-883-00 CARBON 150K 5% 1/4W !R143 1-219-153-11 FUSIBLE 10 5% 1/4W F R144 1-249-435-11 CARBON 33K 5% 1/4W R145 1-249-431-11 CARBON 15K 5% 1/4W R151 1-249-437-11 CARBON 47K 5% 1/4W R152 1-249-433-11 CARBON 22K 5% 1/4W R153 1-249-427-11 CARBON 6.8K 5% 1/4W F R201 1-249-429-11 CARBON 10K 5% 1/4W R202 1-247-887-00 CARBON 220K 5% 1/4W R203 1-249-441-11 CARBON 100K 5% 1/4W R204 1-249-420-11 CARBON 1.8K 5% 1/4W F R205 1-247-843-11 CARBON 3.3K 5% 1/4W R206 1-247-842-11 CARBON 3K 5% 1/4W R207 1-249-417-11 CARBON 1K 5% 1/4W F R208 1-249-427-11 CARBON 6.8K 5% 1/4W F R209 1-249-429-11 CARBON 10K 5% 1/4W R210 1-249-425-11 CARBON 4.7K 5% 1/4W F R211 1-247-881-00 CARBON 120K 5% 1/4W R212 1-247-807-31 CARBON 100 5% 1/4W R213 1-247-882-11 CARBON 130K 5% 1/4W R214 1-247-850-11 CARBON 6.2K 5% 1/4W R215 1-249-433-11 CARBON 22K 5% 1/4W R216 1-247-843-11 CARBON 3.3K 5% 1/4W R217 1-249-429-11 CARBON 10K 5% 1/4W R218 1-249-409-11 CARBON 220 5% 1/4W F R219 1-249-417-11 CARBON 1K 5% 1/4W F R220 1-249-439-11 CARBON 68K 5% 1/4W R221 1-247-881-00 CARBON 120K 5% 1/4W R222 1-247-807-31 CARBON 100 5% 1/4W R223 1-247-882-11 CARBON 130K 5% 1/4W R224 1-247-850-11 CARBON 6.2K 5% 1/4W R225 1-249-440-11 CARBON 82K 5% 1/4W R226 1-249-421-11 CARBON 2.2K 5% 1/4W F R227 1-249-430-11 CARBON 12K 5% 1/4W R228 1-249-417-11 CARBON 1K 5% 1/4W F R229 1-249-421-11 CARBON 2.2K 5% 1/4W F R230 1-249-434-11 CARBON 27K 5% 1/4W R231 1-249-430-11 CARBON 12K 5% 1/4W R232 1-247-883-00 CARBON 150K 5% 1/4W !R233 1-219-153-11 FUSIBLE 10 5% 1/4W F R234 1-249-435-11 CARBON 33K 5% 1/4W R235 1-249-431-11 CARBON 15K 5% 1/4W R241 1-249-430-11 CARBON 12K 5% 1/4W R242 1-247-883-00 CARBON 150K 5% 1/4W !R243 1-219-153-11 FUSIBLE 10 5% 1/4W F R244 1-249-435-11 CARBON 33K 5% 1/4W R245 1-249-431-11 CARBON 15K 5% 1/4W R251 1-249-437-11 CARBON 47K 5% 1/4W R252 1-249-433-11 CARBON 22K 5% 1/4W R253 1-249-427-11 CARBON 6.8K 5% 1/4W F R301 1-249-437-11 CARBON 47K 5% 1/4W R302 1-249-414-11 CARBON 560 5% 1/4W F R303 1-249-437-11 CARBON 47K 5% 1/4W R304 1-249-419-11 CARBON 1.5K 5% 1/4W F R306 1-249-433-11 CARBON 22K 5% 1/4W R309 1-249-433-11 CARBON 22K 5% 1/4W R311 1-249-437-11 CARBON 47K 5% 1/4W R312 1-249-419-11 CARBON 1.5K 5% 1/4W F R313 1-249-414-11 CARBON 560 5% 1/4W F R314 1-249-437-11 CARBON 47K 5% 1/4W R316 1-249-434-11 CARBON 27K 5% 1/4W R317 1-247-862-11 CARBON 20K 5% 1/4W R318 1-249-426-11 CARBON 5.6K 5% 1/4W R341 1-249-429-11 CARBON 10K 5% 1/4W R342 1-249-429-11 CARBON 10K 5% 1/4W R343 1-249-390-11 CARBON 5.6 5% 1/4W F R344 1-249-390-11 CARBON 5.6 5% 1/4W F R345 1-249-440-11 CARBON 82K 5% 1/4W R346 1-249-440-11 CARBON 82K 5% 1/4W R351 1-249-429-11 CARBON 10K 5% 1/4W R352 1-249-425-11 CARBON 4.7K 5% 1/4W F R361 1-247-876-11 CARBON 75K 5% 1/4W R362 1-249-417-11 CARBON 1K 5% 1/4W F R363 1-249-425-11 CARBON 4.7K 5% 1/4W F www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 52 – Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark MAIN R364 1-249-425-11 CARBON 4.7K 5% 1/4W F R371 1-249-417-11 CARBON 1K 5% 1/4W F R372 1-249-429-11 CARBON 10K 5% 1/4W R401 1-249-437-11 CARBON 47K 5% 1/4W R402 1-249-414-11 CARBON 560 5% 1/4W F R403 1-249-437-11 CARBON 47K 5% 1/4W R404 1-249-419-11 CARBON 1.5K 5% 1/4W F R411 1-249-437-11 CARBON 47K 5% 1/4W R412 1-249-419-11 CARBON 1.5K 5% 1/4W F R413 1-249-414-11 CARBON 560 5% 1/4W F R414 1-249-437-11 CARBON 47K 5% 1/4W R416 1-249-434-11 CARBON 27K 5% 1/4W R417 1-247-862-11 CARBON 20K 5% 1/4W R441 1-249-429-11 CARBON 10K 5% 1/4W R442 1-249-429-11 CARBON 10K 5% 1/4W R443 1-249-390-11 CARBON 5.6 5% 1/4W F R444 1-249-390-11 CARBON 5.6 5% 1/4W F R445 1-249-440-11 CARBON 82K 5% 1/4W R446 1-249-440-11 CARBON 82K 5% 1/4W R451 1-249-429-11 CARBON 10K 5% 1/4W R452 1-249-425-11 CARBON 4.7K 5% 1/4W F R461 1-247-876-11 CARBON 75K 5% 1/4W R462 1-249-417-11 CARBON 1K 5% 1/4W F R463 1-249-425-11 CARBON 4.7K 5% 1/4W F R464 1-249-425-11 CARBON 4.7K 5% 1/4W F R471 1-249-417-11 CARBON 1K 5% 1/4W F R472 1-249-429-11 CARBON 10K 5% 1/4W R501 1-215-455-00 METAL 27K 1% 1/4W R502 1-215-452-00 METAL 20K 1% 1/4W R503 1-249-417-11 CARBON 1K 5% 1/4W F R504 1-249-422-11 CARBON 2.7K 5% 1/4W F R505 1-247-903-00 CARBON 1M 5% 1/4W R506 1-249-429-11 CARBON 10K 5% 1/4W R507 1-249-429-11 CARBON 10K 5% 1/4W R508 1-249-413-11 CARBON 470 5% 1/4W F R509 1-249-417-11 CARBON 1K 5% 1/4W F R510 1-249-437-11 CARBON 47K 5% 1/4W R511 1-249-429-11 CARBON 10K 5% 1/4W R512 1-249-413-11 CARBON 470 5% 1/4W F R513 1-249-437-11 CARBON 47K 5% 1/4W R514 1-249-401-11 CARBON 47 5% 1/4W F R515 1-215-455-00 METAL 27K 1% 1/4W R521 1-249-433-11 CARBON 22K 5% 1/4W R522 1-249-426-11 CARBON 5.6K 5% 1/4W R523 1-249-436-11 CARBON 39K 5% 1/4W R524 1-249-425-11 CARBON 4.7K 5% 1/4W F R525 1-249-425-11 CARBON 4.7K 5% 1/4W F R526 1-249-441-11 CARBON 100K 5% 1/4W R527 1-249-441-11 CARBON 100K 5% 1/4W R528 1-249-424-11 CARBON 3.9K 5% 1/4W F R529 1-249-413-11 CARBON 470 5% 1/4W F R530 1-249-429-11 CARBON 10K 5% 1/4W R561 1-249-437-11 CARBON 47K 5% 1/4W R562 1-249-437-11 CARBON 47K 5% 1/4W R563 1-249-437-11 CARBON 47K 5% 1/4W R564 1-249-431-11 CARBON 15K 5% 1/4W R565 1-249-429-11 CARBON 10K 5% 1/4W R571 1-249-418-11 CARBON 1.2K 5% 1/4W F R572 1-249-426-11 CARBON 5.6K 5% 1/4W R573 1-249-427-11 CARBON 6.8K 5% 1/4W F R575 1-247-852-11 CARBON 7.5K 5% 1/4W R576 1-249-430-11 CARBON 12K 5% 1/4W R577 1-249-428-11 CARBON 8.2K 5% 1/4W F R578 1-249-428-11 CARBON 8.2K 5% 1/4W F R579 1-249-426-11 CARBON 5.6K 5% 1/4W R580 1-249-422-11 CARBON 2.7K 5% 1/4W F R581 1-249-425-11 CARBON 4.7K 5% 1/4W F R582 1-249-425-11 CARBON 4.7K 5% 1/4W F R583 1-247-852-11 CARBON 7.5K 5% 1/4W R584 1-249-430-11 CARBON 12K 5% 1/4W R585 1-249-428-11 CARBON 8.2K 5% 1/4W F R586 1-249-428-11 CARBON 8.2K 5% 1/4W F R587 1-249-422-11 CARBON 2.7K 5% 1/4W F R588 1-249-426-11 CARBON 5.6K 5% 1/4W R601 1-249-429-11 CARBON 10K 5% 1/4W R602 1-249-417-11 CARBON 1K 5% 1/4W F R603 1-249-425-11 CARBON 4.7K 5% 1/4W F R604 1-249-429-11 CARBON 10K 5% 1/4W R605 1-249-393-11 CARBON 10 5% 1/4W F R701 1-249-414-11 CARBON 560 5% 1/4W F R703 1-247-843-11 CARBON 3.3K 5% 1/4W R704 1-249-425-11 CARBON 4.7K 5% 1/4W F R705 1-249-427-11 CARBON 6.8K 5% 1/4W F R706 1-249-419-11 CARBON 1.5K 5% 1/4W F R707 1-247-854-11 CARBON 9.1K 5% 1/4W R708 1-249-419-11 CARBON 1.5K 5% 1/4W F R709 1-249-425-11 CARBON 4.7K 5% 1/4W F R710 1-249-417-11 CARBON 1K 5% 1/4W F R711 1-249-427-11 CARBON 6.8K 5% 1/4W F R712 1-249-427-11 CARBON 6.8K 5% 1/4W F R713 1-249-417-11 CARBON 1K 5% 1/4W F R714 1-249-429-11 CARBON 10K 5% 1/4W R715 1-249-422-11 CARBON 2.7K 5% 1/4W F R716 1-249-433-11 CARBON 22K 5% 1/4W R717 1-249-421-11 CARBON 2.2K 5% 1/4W F R718 1-249-429-11 CARBON 10K 5% 1/4W R719 1-249-430-11 CARBON 12K 5% 1/4W !R720 1-219-136-11 FUSIBLE 0.22 10% 1/4W !R722 1-219-137-11 FUSIBLE 0.33 10% 1/4W !R723 1-219-137-11 FUSIBLE 0.33 10% 1/4W R801 1-249-417-11 CARBON 1K 5% 1/4W F R803 1-249-429-11 CARBON 10K 5% 1/4W R804 1-249-429-11 CARBON 10K 5% 1/4W R805 1-247-807-31 CARBON 100 5% 1/4W R806 1-249-433-11 CARBON 22K 5% 1/4W R807 1-249-441-11 CARBON 100K 5% 1/4W R808 1-249-441-11 CARBON 100K 5% 1/4W R809 1-249-417-11 CARBON 1K 5% 1/4W F R810 1-247-807-31 CARBON 100 5% 1/4W R811 1-249-429-11 CARBON 10K 5% 1/4W R812 1-249-429-11 CARBON 10K 5% 1/4W R813 1-247-807-31 CARBON 100 5% 1/4W R830 1-247-807-31 CARBON 100 5% 1/4W R831 1-249-431-11 CARBON 15K 5% 1/4W www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 53 – Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark R832 1-249-429-11 CARBON 10K 5% 1/4W R833 1-249-421-11 CARBON 2.2K 5% 1/4W F R834 1-247-852-11 CARBON 7.5K 5% 1/4W R835 1-247-866-11 CARBON 30K 5% 1/4W R836 1-247-874-11 CARBON 62K 5% 1/4W R837 1-249-434-11 CARBON 27K 5% 1/4W R838 1-249-434-11 CARBON 27K 5% 1/4W R839 1-249-434-11 CARBON 27K 5% 1/4W R840 1-249-434-11 CARBON 27K 5% 1/4W R841 1-249-429-11 CARBON 10K 5% 1/4W R842 1-249-429-11 CARBON 10K 5% 1/4W R843 1-249-429-11 CARBON 10K 5% 1/4W R844 1-249-429-11 CARBON 10K 5% 1/4W R845 1-249-431-11 CARBON 15K 5% 1/4W R846 1-249-429-11 CARBON 10K 5% 1/4W R847 1-247-864-11 CARBON 24K 5% 1/4W R853 1-249-421-11 CARBON 2.2K 5% 1/4W F R854 1-247-852-11 CARBON 7.5K 5% 1/4W R855 1-247-866-11 CARBON 30K 5% 1/4W R856 1-247-874-11 CARBON 62K 5% 1/4W R857 1-249-431-11 CARBON 15K 5% 1/4W R858 1-249-434-11 CARBON 27K 5% 1/4W R859 1-249-434-11 CARBON 27K 5% 1/4W R860 1-249-434-11 CARBON 27K 5% 1/4W R861 1-249-434-11 CARBON 27K 5% 1/4W R863 1-249-429-11 CARBON 10K 5% 1/4W R864 1-249-429-11 CARBON 10K 5% 1/4W R865 1-249-429-11 CARBON 10K 5% 1/4W R866 1-249-429-11 CARBON 10K 5% 1/4W R867 1-247-864-11 CARBON 24K 5% 1/4W R868 1-249-429-11 CARBON 10K 5% 1/4W < VARIABLE RESISTOR > RV101 1-241-765-11 RES, ADJ, CARBON 22K RV102 1-241-765-11 RES, ADJ, CARBON 22K RV111 1-241-764-11 RES, ADJ, CARBON 10K RV121 1-241-764-11 RES, ADJ, CARBON 10K RV131 1-241-765-11 RES, ADJ, CARBON 22K RV141 1-241-765-11 RES, ADJ, CARBON 22K RV201 1-241-765-11 RES, ADJ, CARBON 22K RV202 1-241-765-11 RES, ADJ, CARBON 22K RV211 1-241-764-11 RES, ADJ, CARBON 10K RV221 1-241-764-11 RES, ADJ, CARBON 10K RV231 1-241-765-11 RES, ADJ, CARBON 22K RV241 1-241-765-11 RES, ADJ, CARBON 22K RV316 1-241-764-11 RES, ADJ, CARBON 10K RV317 1-241-765-11 RES, ADJ, CARBON 22K RV318 1-241-764-11 RES, ADJ, CARBON 10K RV416 1-241-764-11 RES, ADJ, CARBON 10K RV417 1-241-765-11 RES, ADJ, CARBON 22K < RELAY > RY351 1-755-061-11 RELAY RY451 1-755-061-11 RELAY < TRANSFORMER > T131 1-433-381-11 TRANSFORMER, BIAS OSCILLATOR T141 1-433-381-11 TRANSFORMER, BIAS OSCILLATOR T231 1-433-381-11 TRANSFORMER, BIAS OSCILLATOR T241 1-433-381-11 TRANSFORMER, BIAS OSCILLATOR T341 1-429-222-11 TRANSFORMER, BIAS OSCILLATION (105kHz) T441 1-429-222-11 TRANSFORMER, BIAS OSCILLATION (105kHz) < TEST PIN > TP331 1-766-276-11 PIN, CONNECTOR (PC BOARD) 3P TP441 1-766-276-11 PIN, CONNECTOR (PC BOARD) 3P < VIBRATOR > X801 1-579-175-11 VIBRATOR, CERAMIC (10MHz) ************************************************************** * A-2007-812-A PANEL BOARD, COMPLETE (EXCEPT SP,MY) ********************** * A-2007-816-A PANEL BOARD, COMPLETE (SP,MY) ********************** (TRANS (A), TRANS (B), DIRECTION, H.P, POWER, RECVOL BOARD are included.) * 3-377-337-11 HOLDER (FL) < CAPACITOR > C001 1-113-925-11 CERAMIC 0.01uF 20% 250V C517 1-162-294-31 CERAMIC 0.001uF 10% 50V C518 1-162-294-31 CERAMIC 0.001uF 10% 50V C751 1-164-159-11 CERAMIC 0.1uF 50V C752 1-137-374-11 FILM 0.047uF 5% 50V C753 1-137-374-11 FILM 0.047uF 5% 50V C901 1-104-665-11 ELECT 100uF 20% 10V C902 1-161-494-00 CERAMIC 0.022uF 25V C903 1-162-207-31 CERAMIC 22PF 5% 50V C904 1-126-160-11 ELECT 1uF 20% 50V < CONNECTOR > * CN001 1-580-230-31 PIN, CONNECTOR (PC BOARD) 2P (SP,MY) * CN002 1-568-226-11 PIN, CONNECTOR 2P (EXCEPT SP,MY) CN901 1-784-733-11 CONNECTOR, FFC 11P < DIODE > D901 8-719-313-43 DIODE SEL6210S-TH10 (SYNCHRO) D902 8-719-313-43 DIODE SEL6210S-TH10 (AUTO) D904 8-719-911-19 DIODE 1SS119-25 D905 8-719-911-19 DIODE 1SS119-25 D906 8-719-911-19 DIODE 1SS119-25 D907 8-719-911-19 DIODE 1SS119-25 D908 8-719-911-19 DIODE 1SS119-25 < FLUORESCENT INDICATOR > FLT901 1-517-263-11 INDICATOR TUBE, FLUORESCENT PANEL MAIN The PANEL board is composed of following boards. (TRANS (A), TRANS (B), DIRECTION, H.P, POWER and RECVOL BOARD) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 54 – < IC > IC901 8-749-014-66 IC NJL56H400A IC902 8-759-547-59 IC M35500BGP < JACK > J502 1-568-519-41 JACK, LARGE TYPE (PHONES) < TRANSISTOR > Q901 8-729-029-94 TRANSISTOR DTC143TSA < RESISTOR > R824 1-249-437-11 CARBON 47K 5% 1/4W (SP,MY) R901 1-249-413-11 CARBON 470 5% 1/4W F R902 1-249-413-11 CARBON 470 5% 1/4W F R904 1-247-807-31 CARBON 100 5% 1/4W R905 1-249-441-11 CARBON 100K 5% 1/4W R906 1-247-807-31 CARBON 100 5% 1/4W R911 1-249-418-11 CARBON 1.2K 5% 1/4W F R912 1-249-420-11 CARBON 1.8K 5% 1/4W F R913 1-249-422-11 CARBON 2.7K 5% 1/4W F R914 1-249-424-11 CARBON 3.9K 5% 1/4W F R915 1-249-427-11 CARBON 6.8K 5% 1/4W F R916 1-249-431-11 CARBON 15K 5% 1/4W R917 1-249-437-11 CARBON 47K 5% 1/4W R921 1-249-418-11 CARBON 1.2K 5% 1/4W F R922 1-249-420-11 CARBON 1.8K 5% 1/4W F R923 1-249-422-11 CARBON 2.7K 5% 1/4W F R924 1-249-424-11 CARBON 3.9K 5% 1/4W F R925 1-249-427-11 CARBON 6.8K 5% 1/4W F R926 1-249-431-11 CARBON 15K 5% 1/4W R927 1-249-437-11 CARBON 47K 5% 1/4W R931 1-249-418-11 CARBON 1.2K 5% 1/4W F R932 1-249-420-11 CARBON 1.8K 5% 1/4W F R933 1-249-422-11 CARBON 2.7K 5% 1/4W F R934 1-249-418-11 CARBON 1.2K 5% 1/4W F R935 1-249-420-11 CARBON 1.8K 5% 1/4W F R936 1-249-422-11 CARBON 2.7K 5% 1/4W F R937 1-249-424-11 CARBON 3.9K 5% 1/4W F R941 1-249-418-11 CARBON 1.2K 5% 1/4W F R942 1-249-420-11 CARBON 1.8K 5% 1/4W F R943 1-249-422-11 CARBON 2.7K 5% 1/4W F R944 1-249-424-11 CARBON 3.9K 5% 1/4W F R945 1-249-427-11 CARBON 6.8K 5% 1/4W F R951 1-249-418-11 CARBON 1.2K 5% 1/4W F R952 1-249-420-11 CARBON 1.8K 5% 1/4W F R953 1-249-422-11 CARBON 2.7K 5% 1/4W F R955 1-249-429-11 CARBON 10K 5% 1/4W R956 1-249-429-11 CARBON 10K 5% 1/4W R957 1-249-429-11 CARBON 10K 5% 1/4W R958 1-249-437-11 CARBON 47K 5% 1/4W R960 1-249-429-11 CARBON 10K 5% 1/4W R961 1-249-429-11 CARBON 10K 5% 1/4W R962 1-249-441-11 CARBON 100K 5% 1/4W < VARIABLE RESISTOR > RV901 1-225-707-11 RES, VAR, CARBON 20K RV902 1-225-619-11 RES, VAR, CARBON 10K < SWITCH > S850 1-762-581-11 SWITCH, AC POWER PUSH (1 KEY)(U) S911 1-762-875-21 SWITCH, KEYBOARD (π (CLEAR)(A DECK)) S912 1-762-875-21 SWITCH, KEYBOARD (P (A DECK)) S913 1-762-875-21 SWITCH, KEYBOARD (· (FRONT)(A DECK)) S914 1-762-875-21 SWITCH, KEYBOARD (ª (BACK)(A DECK)) S915 1-762-875-21 SWITCH, KEYBOARD (REC MUTING (A DECK)) S916 1-762-875-21 SWITCH, KEYBOARD (º (AMS)(B DECK)) S917 1-762-875-21 SWITCH, KEYBOARD (‚ (AMS)(B DECK)) S918 1-762-875-21 SWITCH, KEYBOARD (REC (B DECK)) S921 1-762-875-21 SWITCH, KEYBOARD (π (B DECK)) S922 1-762-875-21 SWITCH, KEYBOARD (P (B DECK)) S923 1-762-875-21 SWITCH, KEYBOARD (· (B DECK)) S924 1-762-875-21 SWITCH, KEYBOARD (ª (B DECK)) S925 1-762-875-21 SWITCH, KEYBOARD (REC MUTING (B DECK)) S926 1-762-875-21 SWITCH, KEYBOARD (º (AMS) RMS - (A DECK)) S927 1-762-875-21 SWITCH, KEYBOARD (‚ (AMS) RMS + (A DECK)) S928 1-762-875-21 SWITCH, KEYBOARD (REC (A DECK)) S931 1-762-875-21 SWITCH, KEYBOARD (RESET (A DECK)) S932 1-762-875-21 SWITCH, KEYBOARD (MEMORY (A DECK)) S933 1-762-875-21 SWITCH, KEYBOARD (FADER) S934 1-762-875-21 SWITCH, KEYBOARD (ARL) S935 1-762-875-21 SWITCH, KEYBOARD (SYNCHRO) S936 1-762-567-11 SWITCH, SLIDE (DOLBY NR OFF-ON-MPX) S937 1-762-608-11 SWITCH, SLIDE (DOLBY NR B-C) S941 1-762-875-21 SWITCH, KEYBOARD (DISPLAY (RMS)) S942 1-762-875-21 SWITCH, KEYBOARD (RMS START (RMS)) S943 1-762-875-21 SWITCH, KEYBOARD (CHECK (RMS)) S944 1-762-875-21 SWITCH, KEYBOARD (SET (RMS)) S945 1-762-875-21 SWITCH, KEYBOARD (A+B REC (START (DECK BP))) S946 1-762-875-21 SWITCH, KEYBOARD (DUBBING A+B, HIGH/NORMAL (START (DECK BP))) S947 1-762-609-11 SWITCH, SLIDE (DIRECTION A/a/RELAY) S951 1-762-875-21 SWITCH, KEYBOARD (RESET (B DECK)) S952 1-762-875-21 SWITCH, KEYBOARD (MEMORY (B DECK)) S953 1-762-875-21 SWITCH, KEYBOARD (DECK A (AUTO CAL (START P))) S954 1-762-875-21 SWITCH, KEYBOARD (DECK B (AUTO CAL (START P))) S960 1-554-118-00 SWITCH, PUSH (1 KEY)(PITCH CON ON/OFF) ************************************************************** MISCELLANEOUS ************* 51 1-751-086-11 WIRE (FLAT TYPE)(13 CORE)(180mm) 52 1-769-976-11 WIRE (FLAT TYPE)(13 CORE)(140mm) !53 1-558-945-21 CORD, POWER (POLAR.SPT-1)(CND) !53 1-575-651-21 CORD, POWER (SP,MY) !53 1-751-535-11 CORD, POWER (UK) Les composants identifiés par une marque ! sont critiques pour la sécurité. Ne les remplacer que par une piéce portant le numéro spécifié. The components identified by mark ! or dotted line with mark ! are critical for safety. Replace only with part number specified. Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark PANEL www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 55 – !53 1-777-107-11 CORD, POWER (AEP) !53 1-777-218-11 CORD, POWER (AUS) !53 1-783-108-11 CORD, POWER (CH) !53 1-783-531-51 CORD, POWER (US) 162 1-769-950-11 WIRE (FLAT TYPE)(11 CORE) FLT901 1-517-263-11 INDICATOR TUBE, FLUORESCENT HRPE1 A-2004-646-C DECK ASSY, HEAD (RECORD/PLAYBACK/ERASE)(DECK A) HRPE2 A-2004-646-C DECK ASSY, HEAD (RECORD/PLAYBACK/ERASE)(DECK B) M1001 A-2004-644-A MOTOR ASSY, CAPSTAN (DECK A) M1002 A-2004-644-A MOTOR ASSY, CAPSTAN (DECK B) !S902 1-692-155-11 SELECTOR, POWER VOLTAGE (SP,MY) !T901 1-431-786-12 TRANSFORMER, POWER (AEP,UK,AUS,CH) !T901 1-431-789-12 TRANSFORMER, POWER (SP,MY) !T901 1-431-788-12 TRANSFORMER, POWER (US,CND) ************************************************************** ACCESSORIES & PACKING MATERIALS ******************************* 1-776-263-51 CORD, CONNECTION (AUDIO) 1-777-241-11 CORD, CONNECTION (CONTROL A1)(CND) 3-866-256-11 MANUAL, INSTRUCTION (ENGLISH) 3-866-256-21 MANUASL, INSTRUCTION (FRENCH, SPANISH) (CND,AEP,SP,MY) 3-866-256-31 MANUAL, INSTRUCTION (GERMAN, DUTCH, SWEDISH, ITALIAN, PORUTGUESE)(AEP) 3-866-256-41 MANUAL, INSTRUCTION (CHINESE)(SP,MY,CH) 3-866-671-11 MANUAL (FOR CONTROL A1) (ENGLISH)(US,UK,AUS) 3-866-671-21 MANUAL (FOR CONTROL A1) (ENGLISH,FRENCH,GERMAN,SPANISH,DUTCH, PORTUGUESE,SWEDISH,ITALIAN, CHINESE) (CND,AEP,SP,MY,CH) ************************************************************** ************* HARDWARE LIST ************* #1 7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S #2 7-685-871-01 SCREW +BVTT 3X6 (S) #3 7-685-851-09 SCREW +BVTT 2X4 (S) #4 7-685-852-04 SCREW +BVTT 2X5 (S) #5 7-685-902-21 SCREW +PTPWH 2.6X8 (TYPE2) #6 7-628-254-15 SCREW +PS 2.6X6 #7 7-623-505-01 LUG, 2 #8 7-685-851-04 SCREW +BVTT 2X4 (S) Les composants identifiés par une marque ! sont critiques pour la sécurité. Ne les remplacer que par une piéce portant le numéro spécifié. The components identified by mark ! or dotted line with mark ! are critical for safety. Replace only with part number specified. Ref. No. Part No. Description Remark www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 56 – Sony Corporation Home A&V Products Company 9-928-828-11 99C0990-1 Printed in Japan © 1999. 3 Published by Quality Assurance Dept. (Shinagawa) TC-WE635 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com
