SERVICE MANUAL STEREO CASSETTE DECK AEP Model UK Model E Model Australian Model SPECIFICATIONS TC-S3 Ver 1.0 2001.04 9-873-837-11 Sony Corporation 2001D0500-1 Home Audio Company C 2001.4 Shinagawa Tec Service Manual Production Group TC-S3 is the Tape deck section in MHC-S7AV/SV7AV/S3. Recording system 4-track 2-channel stereo Frequency response 60 – 13,000 Hz (±3 dB), (DOLBY NR OFF) using Sony TYPE I cassette, 60 – 14,000 Hz (±3 dB), using Sony TYPE II cassette Wow and flutter ±0.15% W.Peak (IEC) 0.1% W.RMS (NAB) ±0.2% W.Peak (DIN) Dimensions (w/h/d) Approx. 280 x 128 x 330 mm Mass Approx. 2.4 kg Design and specifications are subject to change without notice. Tape deck Model Name Using Similar Mechanism NEW Section Tape Transport Mechanism Type TCM-230AWR41/ 230MWR41 Dolby noise reduction manufactured under license from Dolby Laboratories Licensing Corporation. “DOLBY” and the double-D symbol ; are trade- marks of Dolby Laboratories Licensing Corporation. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 2 TC-S3 TABLE OF CONTENTS 1. SERVICING NOTES ................................................ 3 2. GENERAL Location of Controls ....................................................... 4 3. DISASSEMBLY 3-1. Disassembly Flow ........................................................... 6 3-2. Cover ............................................................................... 6 3-3. MAIN Board ................................................................... 7 3-4. Front Panel Section ......................................................... 7 3-5. Tape Mechanism Deck (TCM-230AWR41/230MWR41) .................................... 8 3-6. LEAF SW Board, HEAD (A) Board, HEAD (B) Board ............................................................ 8 4. TEST MODE .............................................................. 9 5. MECHANICAL ADJUSTMENTS ....................... 10 6. ELECTRICAL ADJUSTMENTS ......................... 10 7. DIAGRAMS 7-1. Note for Printed Wiring Boards and Schematic Diagrams ....................................................... 13 7-2. Schematic Diagram – MAIN Section (1/2) – ................ 14 7-3. Schematic Diagram – MAIN Section (2/2) – ................ 15 7-4. Printed Wiring Board – MAIN Section – ...................... 16 7-5. Schematic Diagram – LEAF SW Section – ................. 17 7-6. Printed Wiring Board – LEAF SW Section – ............... 17 7-7. Schematic Diagram – PANEL Section – ....................... 18 7-8. Printed Wiring Boards – PANEL Section – .................. 18 7-9. IC Pin Function Description ........................................... 19 8. EXPLODED VIEWS 8-1. General Section ............................................................... 21 8-2. Front Panel Section ......................................................... 22 8-3. Tape Mechanism Deck Section-1 (TCM-230AWR41/230MWR41) .................................... 23 8-4. Tape Mechanism Deck Section-2 (TCM-230AWR41/230MWR41) .................................... 24 9. ELECTRICAL PARTS LIST ............................... 25 Notes on chip component replacement • Never reuse a disconnected chip component. • Notice that the minus side of a tantalum capacitor may be dam- aged by heat. SAFETY-RELATED COMPONENT WARNING!! COMPONENTS IDENTIFIED BY MARK 0 OR DOTTED LINE WITH MARK 0 ON THE SCHEMATIC DIAGRAMS AND IN THE PARTS LIST ARE CRITICAL TO SAFE OPERATION. REPLACE THESE COMPONENTS WITH SONY PARTS WHOSE PART NUMBERS APPEAR AS SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUB- LISHED BY SONY. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 3 TC-S3 SECTION 1 SERVICING NOTES This set is a component of the MHC-S7AV, MHC-SV7AV and MHC-S3. The MHC-S7AV/SV7AV/S3 system configuration is as shown be- low, and therefore it does not operate normally unless all four com- ponents are connected. In performing the repair, connect all components with the system cables. Note: The precaution to the users is described on the label stuck on the back panel (CD player) and in the troubleshooting section in the Operation Manual. System Configuration: POWER SUPPLY AC IN TA SYSTEM & CD µcon ST CDP TC µcon TC DISPLAY Model PART No. AEP and UK models 4-233-093-0[] Australian, Saudi Arabia and Korean models 4-233-093-1[] Sigapore model 4-233-093-2[] Thailand and Mexican models 4-233-093-3[] • MODEL IDENTIFICATION – Rear Panel – PART No. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 4 TC-S3 SECTION 2 GENERAL This section is extracted from instruction manual. LOCATION OF CONTROLS – Front Panel – 2 1 – Rear Panel – h H AUTO REVERSE h H AUTO REVERSE M > m H . h x M > m H . h x A A th tg tf td ts ta el r; ra rs rd rf rg rh rj rk rl t; CD SYNC rh (20, 21) DIRECTION t; (19, 20, 21) DOLBY NR rl (19, 20) EDIT rk (21) HI-DUB rj (20) REC PAUSE/START rg (20, 21) – Deck A – N (forward play) tf (19, 35) n (reverse play) td (19, 35) x (stop) ts (19) M/> (fast forward/go forward) th (19) m/. (rewind/go back) tg (19) Z (eject) ta (19) – Deck B – N (forward play) ra (19, 20, 35) n (reverse play) rs (19, 20, 35) x (stop) rd (19, 20) M/> (fast forward/go forward) el (19) m/. (rewind/go back) r; (19) Z (eject) rf (19) 1 SYSTEM CONTROL 5 connector (FROM CDP-S3/MCE-VS77) 2 SYSTEM CONTROL 4 connector (FROM ST-S5/S3/VS77) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 5 TC-S3 6 x hH H hH O o P p M m X > . 1 2 3 wg qh qa wk wj wh wa 4 5 6 7 qs qf qd qg 8 9 q; qk ql w; qj wd ws wf es ea e; wl Remote Control CD H es (14, 15) CHECK 5 (15) CLEAR 6 (15) CLOCK/TIMER SELECT qj (30) CLOCK/TIMER SET qk (13, 21, 29) DBFB qg (23) DISPLAY ws (13, 16, 18, 29, 35) D.SKIP 4 (14) ENTER wg (10, 12, 13, 15, 17, 18, 21, 22, 26–30) EQ qd (27) EQ ON/OFF qf (10, 28) FUNCTION wf (10, 14, 15, 20, 21, 31) GROOVE wa (23) SET UP qs (10, 12, 26, 28, 29) SLEEP 7 (29) SUR wd (25) TAPE A hH ea (19, 35) TAPE B hH e; (19, 20, 35) TUNER/BAND wl (17) TUNING + 9 (17) TUNING – wh (17) TV CH +/– ql TV VOL +/– w; TV @/1 2 TV/VIDEO 1 VOL +/– qh BUTTON DESCRIPTIONS @/1 (power) 3 X (pause) q; x (stop) 8 . (go back) wk > (go forward) wj m (rewind) wh M (fast forward) 9 O/o/P/p qa www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com TC-S3 6 • This set can be disassembled in the order shown below. 3-1. DISASSEMBLY FLOW SECTION 3 DISASSEMBLY Note: Follow the disassembly procedure in the numerical order given. 3-2. COVER 3-2. COVER (Page 6) 3-3. MAIN BOARD (Page 7) 3-4. FRONT PANEL SECTION (Page 7) 3-6. LEAF SW BOARD, HEAD (A) BOARD, HEAD (B) BOARD (Page 8) 3-5. TAPE MECHANISM DECK (TCM-230AWR41/230MWR41) (Page 8) SET 2 two screws (case 3 TP2) 3 3 2 two screws (case 3 TP2) 1 three screws (BVTP3 × 8) 4 Remove the cover in the direction of arrow A. A www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com TC-S3 7 3-3. MAIN BOARD 3-4. FRONT PANEL SECTION 2 connector (CN1) 5 MAIN board 1 wire (flat type) (17 core) (CN311) 2 three connectors (CN309, 310, 314) 3 three screws (BVTP3 × 8) 3 screw (BVTP3 × 8) 4 PC board holder 2 connector (CN2) 7 front panel section 2 connector (CN1) 3 screw (BVTP3 × 8) 2 connector (CN314) 1 wire (flat type) (17 core) (CN311) 4 lug 6 two claws 2 connector (CN2) 6 three claws 5 three screws (BVTP3 × 8) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com TC-S3 8 3-5. TAPE MECHANISM DECK (TCM-230AWR41/230MWR41) 2 five screws (BVTP2.6 × 8) 4 tape mechanism deck (TCM-230AWR41/230MWR41) 1 Open the cassette holder (L)/(R). 3 lug 3-6. LEAF SW BOARD, HEAD (A) BOARD, HEAD (B) BOARD 6 screw (+PTT 2 × 4) 4 screw (+PTT 2 × 4) 3 LEAF SW board 2 five claws 5 head (A) board 7 head (B) board 1 Remove the four solderings. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 9 TC-S3 SECTION 4 TEST MODE Note: Use following buttons in the test mode. no mark : Button of Tape unit (TC-S3) *1 : Button of amplifier unit (TA-S7AV or TA-S3) *2 : Button of CD unit (CDP-S3) [MC Test Mode] Enter the MC Test Mode Procedure: 1. Press the I/1 *1 button to turn the power on. 2. While pressing the both [PLAY MODE]*2 and [ ]*2 buttons, press the [DISC 3]*2 button. 3. “GROOVE” indication blinks on the fluorescent indicator tube in the midst of MC test mode. Releasing the MC Test Mode To release from this mode, press the I/1 *1 button or disconnect the power cord. [DECK Test Mode] In the DECK test mode, it operates as follows. Cancellation of the linear mute of DOLBY IC (IC301) • It become cancellation automatically when it is possible to en- ter a MC test mode. AMS checking Procedure: 1. Enter the MC test mode. 2. Insert a test tape AMS-110A or AMS-120 to Deck A. 3. Set TAPE A function. 4. Press the [CD SYNC] button to enter the AMS test mode. 5. After a tape is rewound first, the FF AMS is checked, and the mechanism is shut off after detecting the ASM signal twice. 6. Then the REW AMS is checked and the mechanism is shut off after detecting the AMS signal twice. 7. When the check is complete, a message of either OK or NG appears. (To check an AMS of the B deck, select TAPE B function. After that, press [CD SYNC].) x ALC checking Procedure: 1. Enter the MC test mode. 2. Insert a tape into Deck B. 3. During Recording, Keep holding down the below keys. [ ]*2 + [REC PAUSE/START] ALC could keep ON while these keys keep being pressed, ALC could keep OFF while keys are released. Double speed REC mode Procedure: 1. Enter the MC test mode 2. Insert a tape into Deck B. 3. During Recording, keep holding down the below key. [HI-DUB] Double speed recording is going on while the key keeps being pressed. REC/PLAY checking • The mode to PLAY by rewinding recording contents automati- cally. Procedure: 1. If recording A surface, it returns automatically at the point of the recording beginning and it replays when pressing TAPE B [ ]. 2. If recording B surface, it returns automatically at the point of the recording beginning and it replays when pressing TAPE B [ ]. x M m www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 10 TC-S3 SECTION 5 MECHANICAL ADJUSTMENTS SECTION 6 ELECTRICAL ADJUSTMENTS 0 dB=0.775 V DECK SECTION 1. Demagnetize the record/playback head with a head demagnetizer. 2. Do not use a magnetized screwdriver for the adjustments. 3. After the adjustments, apply suitable locking compound to the parts adjust. 4. The adjustments should be performed with the rated power supply voltage unless otherwise noted. 5. The adjustments should be performed in the order given in this service manual. (As a general rule, playback circuit ad- justment should be completed before performing recording circuit adjustment.) 6. The adjustments should be performed for both L-CH and R- CH. 7. Switches and controls should be set as follows unless other- wise specified. 8. Please refer to “SERVICING NOTES” (page 3) before adjust- ments. • Test Tape Tape Signal Used for P-4-A100 10 kHz, –10 dB Azimuth Adjustment WS-48B 3 kHz, 0 dB Tape Speed Adjustment P-4-L300J 315 Hz, 0 dB Level Adjustment DECK A DECK B Record/Playback Head Azimuth Adjustment Note: Perform this adjustments for both decks Procedure: 1. Mode: Playback Precaution 1. Clean the following parts with a denatured alcohol-moistened swab: record/playback heads pinch rollers erase head rubber belts capstan idlers 2. Demagnetize the record/playback head with a head demagne- tizer. 3. Do not use a magnetized screwdriver for the adjustments. 4. After the adjustments, apply suitable locking compound to the parts adjusted. 5. The adjustments should be performed with the rated power supply voltage unless otherwise noted. Torque Measurement set ST- S3/S5/SV7 test tape P-4-A100 (10 kHz, –10 dB) + – level meter MD OUT jack (J601) 3.06 N • m to 6.96 N • m 31 to 71 g • cm (0.43 – 0.98 oz • inch) 0.19 N • m to 0.58 N • m 2 to 6 g • cm (0.02 – 0.08 oz • inch) 3.06 N • m to 6.96 N • m 31 to 71 g • cm (0.43 – 0.98 oz • inch) 0.19 N • m to 0.58 N • m 2 to 6 g • cm (0.02 – 0.08 oz • inch) 6.96 N • m to 14.02 N • m 71 to 143 g • cm (0.98 – 1.99 oz • inch) 9.80 N • m 100 g or more (3.53 oz or more) 9.80 N • m 100 g or more (3.53 oz or more) Mode Torque meter CQ-102C CQ-102C CQ-102RC CQ-102RC CQ-201B CQ-403A CQ-403R Meter reading FWD FWD back tension REV REV back tension FF/REW FWD tension REV tension www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 11 TC-S3 2. Turn the adjustment screw and check output peaks. If the peaks do not match for L-CH and R-CH, turn the adjustment screw so that outputs match within 1dB of peak. 3. Mode: Playback 4. After the adjustments, apply suitable locking compound to the pats adjusted. Adjustment Location: Playback Head (Deck A). Record/Playback/Erase Head (Deck B). Note: Use following buttons in the test mode. no mark : Button of Tape unit (TC-S3) *1 : Button of amplifier unit (TA-S7AV or TA-S3) *2 : Button of CD unit (CDP-S3) Tape Speed Adjustment DECK B Note: Start the Tape Speed adjustment as below after setting to the test mode. In the test mode, the tape speed is high during pressing the [HI-DUB] button. Procedure: 1. Turn the power switch on. 2. While pressing the both [PLAY MODE]*2 and [ ]*2 buttons, press the [DISC 3]*2 button. (The “GROOVE” on the fluorescent indicator tube display while in the test mode.) To exit from the test mode, press the ?/1 *1 button. Mode: Playback 1. Insert the WS-48B into the deck B. 2. Press the N button on the deck B. 3. Press the [HI-DUB] button in playback mode. Then at HIGH speed mode. 4. Adjust RV1001 on the LEAF SW board so that frequency counter reads 6,000 ± 30 Hz. 5. Press the [HI-DUB] button. Then back to NORMAL speed mode. 6. Adjust RV1002 on the LEAF SW board so that frequency counter reads 3,000 ± 15 Hz. Adjustment Location: LEAF SW board Playback level Adjustment DECK A DECK B Procedure: Mode: Playback 1. Confirm that level difference between the channels is with ± 0.5 dB. 2. After check, adjust the following RVs. Deck A is RV302 (L-CH), Deck B is RV303 (L-CH) so that adjustment within adjustment level as follows. Adjustment Level: MD OUT jack (J601) PB level: 334.4 to 748.7 mV (–6.8 ± 0.5 dB) Adjustment Location: MAIN board Sample Volue of Wow and Flutter: 0.3% or less W. RMS (WS-48B) Screw position L-CH peak within 1dB Output level L-CH peak R-CH peak within 1dB Screw position R-CH peak set test tape P-4-A100 (10 kHz, –10 dB) oscilloscope L-CH R-CH waveform of oscilloscope in phase 45° 90° 135° 180° good wrong ST- S3/S5/SV7 MD OUT jack (J601) + – + – set test tape WS-48B (3 kHz, 0 dB) frequency counter ST- S3/S5/SV7 MD OUT jack (J601) set test tape P-4-L300J (315 Hz, 0 dB) ST- S3/S5/SV7 + – level meter MD OUT jack (J601) reverse forward x www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 12 TC-S3 Adjustable level: MD OUT jack PB level: 47.2 to 53.0 mV (–27.3 to –26.3 dB) Adjustment Location: MAIN board [MAIN BOARD] (Component Side) [LEAF SW BOARD] (Component Side) REC Bias Adjustment DECK B Procedure: 1. Insert a tape into Deck B. 2. After press [REC PAUSE/START] button, press [REC PAUSE/START] button, then recording start. 3. Mode: Record 4. Mode: Playback 5. Confirm the playback signal recorded in step 3 becomes ad- justable level as follows. If these levels are not adjustable level, adjust the RV304 (L- CH) and RV354 (R-CH) on the MAIN board to repeat steps 4 and 5. Adjustable level: Playback output of 315 Hz to playback output of 10 kHz: ±1.0 dB Adjustment Location: MAIN board REC Level Adjustment DECK B Procedure: 1. Insert a tape into Deck B. 2. After press [REC PAUSE/START] button, press [REC PAUSE/START] button, then recording start. 3. Mode: Record 4. Mode: Playback 5. Confirm the play back signal recorded in step 3 becomes ad- justable level as follows. If these levels are not adjustable level, adjust the RV301 (L- CH) and RV351 (R-CH) on the MAIN board to repeat steps 4 and 5. attenuator set MD/VIDEO (AUDIO) IN (J601): ST-S3/S5/SV7 1) 315 Hz 2) 10 kHz 50 mV (–23.8 dB)    600 Ω blank tape CN-123 AF OSC ST- S3/S5/SV7 + – set recorded portion level meter MD OUT jack (J601) ST- S3/S5/SV7 MD/VIDEO (AUDIO) IN (J601) : ST-S3/S5/SV7 315 Hz, 50 mV (–23.8 dB) blank tape CS-123 attenuator set 600 Ω AF OSC ST- S3/S5/SV7 + – set recorded portion level meter MD OUT jack (J601) ST- S3/S5/SV7 TAPE SPEED RV1002 RV1001 (NORMAL) (HIGH) CN1001           DECK A PB LEVEL (L-CH) REC LEVEL (R-CH) DECK B PB LEVEL (L-CH) REC LEVEL (L-CH) REC BIAS (R-CH) REC BIAS (L-CH) RV302 RV303 RV354 RV304 RV301 RV351 CN311 IC303 IC302 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com TC-S3 13 13 SECTION 7 DIAGRAMS 7-1. NOTE FOR PRINTED WIRING BOARDS AND SCHEMATIC DIAGRAMS Note on Printed Wiring Boards: • X : parts extracted from the component side. • : Pattern from the side which enables seeing. • Indication of transistor. B These are omitted. C E Q B These are omitted. C E Q Note on Schematic Diagram: • All capacitors are in µF unless otherwise noted. pF: µµF 50 WV or less are not indicated except for electrolytics and tantalums. • All resistors are in Ω and 1/4 W or less unless otherwise specified. • 5 : fusible resistor. • C : panel designation. • A : B+ Line. • B : B– Line. • Voltages and waveforms are dc with respect to ground under no-signal conditions. no mark : STOP ( ) : PB 〈〈 〉〉 : REC • Voltages are taken with a VOM (Input impedance 10 MΩ). Voltage variations may be noted due to normal produc- tion tolerances. • Waveforms are taken with a oscilloscope. Voltage variations may be noted due to normal produc- tion tolerances. • Circled numbers refer to waveforms. • Signal path. E : PB a : REC Note: The components identified by mark 0 or dotted line with mark 0 are critical for safety. Replace only with part number specified. • Waveforms – MAIN Board – 1 T301 4 (DECK-B REC mode) 2 Q301, 303 (collector) (REC mode) 3 NO312 6 (L-REC), 3 (R-REC) (DECK-B REC mode) 120 Vp-p 13 µs 10 Vp-p 13 µs 52 Vp-p 13 µs • IC Block Diagram – MAIN Board – IC302 µPC1330HA 1 2 3 4 5 6 7 8 9 INVERTER COMPARATER SW R1 GND SW P1 CONT GND VCC SW P2 GND SW R2 • Circuit Boards Location LEAF SW board HEAD (A) board HEAD (B) board TC-SUB PANEL-A board TC-SUB PANEL-B board TC-PANEL-A DECK board TC-PANEL-B DECK board MAIN board w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com TC-S3 14 14 7-2. SCHEMATIC DIAGRAM – MAIN Section (1/2) – • See page 13 for Waveforms. • See page 13 for IC Block Diagram. The components identified by mark 0 or dotted line with mark 0 are critical for safety. Replace only with part number specified. CN314 R386 TP405 TP406 TP407 TP408 TP409 C335 T301 C336 R342 R343 Q302 C337 R344 C338 R345 C339 C340 R346 C341 C342 L302 L303 R369 C350 C349 C348 R368 R367 C384 C334 RV354 C382 L351 C383 C333 L301 C332 R321 R349 R348 C347 C367 Q304 Q305 TP344 TP343 TP345 TP346 TP347 TP348 C372 R371 C386 R372 C373 R373 R370 C371 TP342 TP341 TP340 C321 R330 C385 R331 R332 C323 R333 C322 C324 RV302 C374 C378 R376 R377 R378 R379 C379 R338 C329 R339 R337 C377 R375 C376 R336 C328 R335 R334 R340 C330 RV303 C380 R402 R403 R404 R405 Q301 Q310 R341 R347 TP370 Q303 C327 C326 RV304 CN1 HP901 HRPE901 CN2 IC304(2/2) IC304(1/2) IC303(2/2) IC303(1/2) NO313 NO312 IC302 R374 R380 7P 270 0.01 100V 2.2 50V 5.6 5.6 2SC2001 0.015 18k 0.0068 18k 0.0068 0.018 5.6k 1 50V 47 16V 470 10 50V 10 50V 0.1 1.2k 1k 27p 27p 220k 120p 27mH 330p 330p 27mH 120p 12k 4.7k 220 10 50V 0.001 BN1A4M BA1A4M 100p 100 100 10V 5.6k 0.022 130k 120k 390p 390p 120k 100 10V 100 5.6k 0.022 130k 100p 100 16V 2.2k 100 16V 100p 220 22k 12k 270k 0.01 12k 0.01 270k 22k 100 10V 120k 390p 220 100p 120k 220 220 100 16V 2.2k 100 16V 1.5k 820 1.5k 820 2SD1387 2SC2785 12k 22k 2SC2001 100 10V 390p 220k NJM4580MD-D NJM4580MD-D NJM4580MD-D NJM4580MD-D 3P 8P JW JW 1 2 3 4 5 6 7 8 Y6 B-FWD B-REV A-REV A-FWD T1 T2 T4 T5 T6 T3 T7 SW.R1 GND GND GND SW.P1 CONT. VCC SW.P2 SW.R2 L-PB R-PB +6V L-PB L-REC R-PB E-HOT R-REC E+6V E+6V E+6V D+5V DGND 5 6 8 7 3 2 4 1 DECK B PB AMP 5 6 7 4 8 3 2 1 DECK A PB AMP REC/PB SWITCH REC/PB SWITCH Q304,305 CONTROL CONTROL REC BIAS LEVEL SHIFT Q302,303 BIAS OSC L-PB +6V R-PB L-PB E+6V L-REC R-PB E+6V R-REC E-HOT E+6V L-CH R-CH TAPE ERASE R-CH L-CH (REC/PB/ERASE) (DECK B) (DECK A) (PB) MECHANISM DECK (CHASSIS) (CHASSIS) BLOCK TCM-230AWR41 /230MWR41 LED-B-FWD KEY1 LED-B-REV LED-A-REV LED-A-FWD µPC1330HA 220µH 220µH (Page 18) (Page 15) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com TC-S3 15 15 7-3. SCHEMATIC DIAGRAM – MAIN Section (2/2) – TP351 TP352 TP353 RV351 R357 R358 C354 R355 C356 C357 C358 C359 C311 R309 R310 C312 R308 C304 R305 RV301 R307 C318 C306 C307 C308 C309 R318 R319 C301 R300 C319 R303 C370 R350 C395 R351 C360 C353 TP356 CN310 CN309 CN308 EPT300 EPT302 TP320 TP321 TP322 TP323 TP324 TP325 TP326 TP327 TP328 CN311 TP329 TP330 TP331 TP332 TP334 TP333 TP335 TP336 R323 R325 R328 R327 C390 C391 C414 C415 R418 R419 C388 C389 R363 R364 TP394 TP393 TP392 TP391 TP390 TP389 R422 R423 R420 R421 C345 C346 TP395 TP396 TP397 TP398 TP399 TP400 TP401 TP402 TP404 TP386 TP385 TP384 TP383 TP382 TP381 TP380 TP379 TP378 TP377 C398 C399 C343 R324 R315 C316 R316 R313 R311 C315 R317 C344 C396 C397 TP371 TP372 TP373 TP374 TP375 TP376 TP308 TP307 TP306 TP305 TP304 C418 R406 D307 D309 D308 D306 TP318 TP303 TP302 TP301 TP300 TP309 TP310 TP311 TP312 TP313 TP314 TP315 TP316 TP317 TP354 C394 C303 R301 C310 C363 R362 R361 Q393 R359 R360 C362 Q391 Q392 Q394 R322 IC320 Q400 R413 R414 R415 R407 R408 R409 R416 R417 R412 Q395 Q396 IC301 C314 C313 TP355 C352 C317 C320 C302 R314 R354 C305 R304 C355 R356 C368 R302 C369 C351 C417 IC310 IC311 R306 IC321 10k 3.3k 33k 0.1 10k 1 50V 1 50V 10 50V 0.47 10 50V 1M 160k 0.47 50V 22k 0.1 10k 10k 3.3k 10 50V 1 50V 1 50V 10 50V 0.47 1.2k 4.7k 1 50V 22k 2.2 50V 100 2.2 50V 22k 10 50V 2.2k 470p 0.1 10P 5P 5P 17P 4.7k 47k 47k 4.7k 10 50V 470 16V 10 50V 470 10V 560 1k 10 50V 470 16V 47k 1k 220 220 220 220 0.1 0.1 100p 100p 0.1 10k 10k 100 16V 10k 10k 100k 4.7 50V 390k 0.1 100p 100p 0.1 100 11ES2-NTA2B 11ES2-NTA2B 11ES2-NTA2B 11ES2-NTA2B 10 50V 0.1 2.2k 470p 0.0047 1k 1k 2SB1116 1k 1k 0.0047 2SB1116 BA1A4M BA1A4M 47k BA12T 2SC2001 100 100 100 100 100 100 100 100 100 BA1A4M 2SD1387 HA12226F 10 50V 0.001 0.0047 100 10V 2.2 50V 0.0047 33k 6.8k 0.47 50V 6.8k 0.47 50V 12k 10 50V 100 2.2 50V 1 50V 0.1 PT8300-S PT8300-S 12k NJM7809FA 1 2 3 4 5 6 7 8 19 17 19 17 AHALF APLAY BPLAY AHALF BPLAY APLAY LM NR RM BIAS N/H PB ALC ALC PB N/H BIAS RM NR A-REV A-FWD B-FWD B-REV Z1 Z2 Z3 Z4 Z5 Z6 Z7 Z1 Z2 Z3 Z4 Z5 Z6 Z7 Y1 Y2 Y1 Y2 Y4 Y5 Y6 Y7 Y8 Y3 Y3 Y4 Y5 Y7 Y8 LM X1 X2 X3 X4 X1 X2 X3 X4 X5 T1 T2 T3 T4 T5 T6 T7 X5 TCREC-L TCREC-R PB-L PB-R AGND ASHUT BSHUT BHALF REC/PB/PAS D GND CLK LAT DATA-OUT DATA-IN KEY BTRIG ATRIG UNREG HI M GND M GND +5V +12V REGULATOR +9V REGULATOR SHIFT LEVEL (CHASSIS) SYSTEM CONTROL SYSTEM CONTROL 4 ST-S5/S3/VS77 FROM FROM CDP-S3/MCE-VS77 (CHASSIS) SYSTEM CONTROL 5 CAPSTAN CAPSTAN MOTOR SPEED CONTROL MOTOR DRIVE Q391-394 TRIGER DRIVE PB AMP, REC EQ AMP, DOLBY B NR LED DRIVE, MOTOR DRIVER CAP.M H/N TRG/A TRG/GND CAPM(-) CAPM(+) TRG/B A SHUT D.GND A HALF A 120/170 B SHUT A PLAY.SW B HALF B 120/170 B PLAY.SW B METAL (Page 14) (Page 17) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com TC-S3 16 16 7-4. PRINTED WIRING BOARDS – MAIN Section – • See page 13 for Circuit Boards Location. • Semiconductor Location Ref. No. Location D306 H-2 D307 I-6 D308 H-2 D309 H-5 IC301 F-3 IC302 B-4 IC303 C-1 IC304 B-3 IC310 F-6 IC311 E-6 IC320 H-3 IC321 H-4 Q301 B-6 Q302 B-6 Q303 B-6 Q304 B-5 Q305 C-5 Q310 C-6 Q391 C-5 Q392 D-5 Q393 D-5 Q394 D-5 Q395 E-4 Q396 D-4 Q400 H-5 R422 R415 C345 R324 JW305 JW307 JW306 JW308 JW321 JW388 R341 C347 CN314 CN308 JW310 RV302 C380 C377 C330 C327 R340 R405 R404 R339 R378 R338 R336 JW313 JW349 R408 JW383 C346 R418 JW323 JW318 JW374 JW312 JW326 C384 C367 D309 D308 C342 C336 R345 JW382 C341 JW353 R369 R368 JW311 C383 C382 C349 R386 R321 JW354 L351 RV304 R349 R348 IC303 IC304 R347 C397 D307 R325 Q303 Q302 Q301 R367 R360 JW350 R361 C394 Q391 R417 R328 JW380 Q396 JW379 JW360 Q395 Q392 Q394 Q393 R310 R309 C358 C311 C357 C368 C356 C355 R307 R306 R414 R304 C376 JW335 C304 C352 C309 R420 C312 R364 C340 C339 C338 C337 C335 C379 C329 JW319 R407 C354 C353 C302 JW351 JW331 JW369 R362 R359 R357 R358 R356 R355 JW316 R334 C378 JW304 R335 R375 R376 R344 C363 R351 JW363 JW359 R350 JW301 RV303 Q305 R303 C351 C317 C370 C369 C320 C319 JW320 JW309 C343 C301 R300 R301 JW338 JW341 C359 C318 C308 C307 C306 C305 R317 R318 R319 R323 R327 JW377 JW332 R423 R346 R311 R322 JW348 R314 C313 JW358 C316 C315 C314 R412 C399 JW362 R308 JW337 C310 EPT300 R409 C414 C390 C388 C415 C391 C389 R416 JW324 JW336 JW322 IC302 JW325 C398 R363 JW302 R406 JW352 R315 CN309 CN310 CN311 JW364 R413 IC320 IC321 JW371 R305 C322 JW378 JW345 JW339 JW373 C303 JW368 R419 RV354 JW333 RV351 C372 Q304 JW314 T301 1 6 2 5 3 4 JW381 R421 C360 C362 R342 C333 R343 Q310 JW342 R377 C350 D306 R403 R402 C326 C374 C324 C386 C385 Q400 C321 R371 R332 R331 R330 R373 R372 R370 C371 R337 L301 C373 C323 R333 JW346 C328 JW303 C332 JW376 JW365 JW329 C334 JW343 JW328 JW372 C396 C344 JW370 JW355 JW361 JW366 JW344 JW340 JW330 JW367 JW375 JW327 JW334 R313 JW347 R302 JW357 JW356 RV301 R316 C395 JW385 C417 EPT302 NO313 NO312 C418 JW386 C348 L303 L302 R379 IC311 IC301 IC310 R354 JW317 MAIN BOARD 4 1 1 3 5 8 4 1 5 8 42 43 15 14 1 56 28 29 1 9 8 1 B TC-PANEL-B DECK BOARD NO304 E E E E E E E E E E E E 7 (CHASSIS) 5 1 4 2 (CHASSIS) SYSTEM CONTROL 4 FROM ST-S5/S3/VS77 1 3 1 3 E 1-680-718- 1 1 10 5 SYSTEM CONTROL 5 FROM CDP-S3/MCE-VS77 A LEAF SW BOARD CN1001 11 (11, 12) A B C D E F G H I 1 2 3 4 5 6 7 8 9 10 HEAD (A) BOARD HEAD (B) BOARD (Page 17) (Page 18) There are a few cases that the part printed on this diagram isn’t mounted in this model. w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com TC-S3 17 17 7-5. SCHEMATIC DIAGRAM – LEAF SW Section – 7-6. PRINTED WIRING BOARD – LEAF SW Section – • See page 13 for Circuit Boards Location. PM901 PM902 A CN311 IC1001 IC1002 A B C D 1 2 3 4 5 6 7 8 9 10 11 12 (Page 16) D1001 B-4 D1002 B-10 IC1001 B-2 IC1002 B-9 Q1001 B-3 • Semiconductor Location Ref. No. Location C1001 33 10V S1004 (A. 120/70) S1008 (B. 120/70) A MAIN BOARD (2/2) CN311 There are a few cases that the part printed on this diagram isn’t mounted in this model. • Voltages are dc with respect to ground under no-signal conditions. no mark : TAPE PLAY ( ) : TAPE REC (Page 15) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com TC-S3 18 18 7-7. SCHEMATIC DIAGRAM – PANEL Section – 7-8. PRINTED WIRING BOARDS – PANEL Section – • See page 13 for Circuit Boards Location. S316 S312 S313 S314 S315 D301 D300 R398 JW384 R400 R401 R399 S309 S308 R391 R392 R393 R394 S306 S307 S305 S303 S304 S302 S301 D303 D302 R388 R387 R390 R389 S310 S311 R395 R396 R397 LP301 NO304 TC-PANEL-B DECK BOARD TC-SUB PANEL-B BOARD TC-PANEL-A DECK BOARD TC-SUB PANEL-A BOARD M > . m N N n n x NO303 NO302 1 5 1-680-720- 11 (11, 12) 7 1 B MAIN BOARD CN314 NO303 NO302 1 5 REC PAUSE /START CD SYNC DOLBY NR DIRECTION HI-DUB EDIT 5 1 1-680-722- 1-680-721- 1-680-719- 1 5 NO301 NO301 5 1 5 1 M > . m N N n n x A B C 1 2 3 4 5 6 7 11 (11, 12) 11 (11, 12) 11 (11, 12) (Page 16) D300 B-6 D301 C-6 D302 B-1 D303 C-1 • Semiconductor Location Ref. No. Location S301 S302 R387 R388 R389 R390 S303 S304 S305 D302 D303 R391 R392 R393 R394 S306 S307 S308 S309 S311 S310 R396 R397 R395 D301 D300 S316 S315 S314 S313 S312 R398 R399 R400 R401 NO303 NO303 NO302 NO302 NO301 NO301 NO304 330 470 560 680 SEL5423E-T P15 SEL5423E-T P15 1k 1.2k 1.8k 2.7k 4.7k 6.8k 3.3k SEL5423E-T P15 SEL5423E-T P15 10k 15k 27k 56k 5P 5P 5P 5P 5P 5P 7P B FWD B REV A REV A FWD A REV A FWD A REV A FWD A REV A FWD A FWD A REV A FWD A REV B REV B FWD D+5V DGND KEY1 LED-A-FWD LED-A-REV D+5V DGND KEY1 LED-A-REV LED-A-FWD D+5V DGND KEY1 LED-A-FWD LED-A-REV D+5V DGND KEY1 LED-B-FWD LED-B-REV LED-A-REV LED-A-FWD D+5V DGND KEY1 LED-A-REV LED-A-FWD D+5V DGND KEY1 LED-A-FWD LED-A-REV D+5V DGND KEY1 LED-A-FWD LED-A-REV DIRECTION DOLBY NR S311 S310 S307 CD SYNC S308 HI DUB S309 EDIT REC PAUSE/ START S306 S301 S302 S303 S304 S305 S316 S315 S313 S314 S312 D300,301 BACK LIGHT BACK LIGHT D302,303 (Page 14) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 19 TC-S3 7-9. IC PIN FUNCTION DESCRIPTION • MAIN BOARD IC310 PT8300-S (SYSTEM CONTROL) Pin No. Pin Name I/O Description 1 VSS — Ground terminal 2 RESET_B I Reset signal input terminal Not used 3 CLK I Serial data transfer clock signal input from the CD player section (CDP-S3) 4 LATCH I Serial data latch pulse signal input from the CD palyer section (CDP-S3) 5 – 8 P15 – P12 I Not used (fixed at “L”) 9 P11 I AMS signal input terminal “L”: AMS in 10 P10 I Detection input from the deck-A half detect switch “H”: cassette in, “L”: no cassette 11 P9 I Detection input from the deck-B play detect switch “H”: deck-B play 12 P8 I Detection input from the deck-A play detect switch “H”: deck-A play 13 LATCHO O Serial data latch pulse output to the PT8300-S (IC311) 14 CLKO O Serial data transfer clock signal output to the PT8300-S (IC311) 15 DO1 O Serial data output to the PT8300-S (IC311) 16 DI2 I Serial data input from the PT8300-S (IC311) 17 P7 O Tape deck relay on/off control signal output to the µPC1330H (IC302) 18 P6 O ALC on/off control signal output to the HA12226F (IC301) 19 P5 O Deck-A/B selection signal output to the HA12226F (IC301) 20 P4 O EQ high/normal selection signal output to the HA12226F (IC301) 21 P3 O Recording bias on/off control signal output to the HA12226F (IC301) 22 P2 O Recording muting on/off control signal output to the HA12226F (IC301) 23 P1 O Dolby NR on/off selection signal output to the HA12226F (IC301) 24 P0 O Tape deck line muting on/off control output to the HA12226F (IC301) 25 DO2 O Serial data output to the CD player section (CDP-S3) 26 DI1 I Serial data input from the CD player section (CDP-S3) 27 PULLUP I P8 to P15 Control pin for pull-up resisitor (fixed at “L”) 28 VCC — Power supply terminal (+5V) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 20 TC-S3 • MAIN BOARD IC311 PT8300-S (LED DRIVE, MOTOR DRIVER) Pin No. Pin Name I/O Description 1 VSS — Ground terminal 2 RESET_B I Reset signal input terminal Nor used 3 CLK I Serial data transfer clock signal input from the PT8300-S (IC310) 4 LATCH I Serial data latch pulse input from the PT8300-S (IC310) 5 P15 O Not used (connected to pin 6) 6 P14 O LED drive signal output of the B-FWD indicator (D302) “L”: LED on 7 P13 O Not used (connected to pin 8) 8 P12 O LED drive signal output of the B-REV indicator (D303) “L”: LED on 9 P11 O Not used (connected to pin q;) 10 P10 O LED drive signal output of the A-REV indicator (D301) “L”: LED on 11 P9 O Not used (connected to pin qs) 12 P8 O LED drive signal output of the A-FWD indicator (D300) “L”: LED on 13 LATCHO O Not used (open) 14 CLKO O Not used (open) 15 DO1 O Not used (open) 16 DI2 I Not used (fixed at “L”) 17 – 21 P7 – P3 O Not used (open) 22 P2 O Not used (connected to pin wd) 23 P1 O Capstan motor on/off control signal output terminal “H”: motor on 24 P0 O High/normal speed selection signal output of the capstan motor “H”: normal speed, “L”: high speed 25 DO2 O Serial data output to the PT8300-S (IC310) 26 DI1 I Serial data input from the PT8300-S (IC310) 27 PULLUP I P8 to P15 Control pin for Pull-up resistor (fixed at “L”) 28 VCC — Power supply terminal (+5V) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 21 TC-S3 SECTION 8 EXPLODED VIEWS • Items marked “*” are not stocked since they are seldom required for routine service. Some delay should be anticipated when ordering these items. • The mechanical parts with no reference num- ber in the exploded views are not supplied. • Hardware (# mark) list is given in the last of the electrical parts list. NOTE: • -XX and -X mean standardized parts, so they may have some difference from the original one. • Color Indication of Appearance Parts Example: KNOB, BALANCE (WHITE) . . . (RED) ↑ ↑ Parts Color Cabinet's Color • Abbreviation AUS : Australian model EA : Saudi Arabia model KR : korean model MX : Mexican model SP : Singapore model TH : Thailand model 8-1. GENERAL SECTION 5 4 6 7 8 1 2 3 4 not supplied not supplied Front panel section #1 #1 #1 #1 #3 #1 #1 Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark * 1 4-924-098-01 HOLDER, PC BOARD 2 1-773-048-11 WIRE (FLAT TYPE) (17 CORE) 3 A-2007-873-A MAIN BOARD, COMPLETE (EXCEPT TH) 3 A-4725-734-A MAIN BOARD, COMPLETE (TH) 4 3-363-099-21 SCREW (CASE 3 TP2) 5 4-232-336-31 COVER 6 1-757-632-11 CORD (WITH CONNECTOR) 15P 7 4-233-093-01 PANEL (TC), BACK (AEP, UK) 7 4-233-093-11 PANEL (TC), BACK (AUS, EA, KR) 7 4-233-093-21 PANEL (TC), BACK (SP) 7 4-233-093-31 PANEL (TC), BACK (MX, TH) 8 4-965-822-01 FOOT www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 22 TC-S3 8-2. FRONT PANEL SECTION Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 51 X-4953-607-1 PANEL ASSY, FRONT 52 X-4953-606-1 HOLDER (R) ASSY, CASSETTE 53 4-233-091-01 SPRING (R), TORSION 54 4-233-090-01 SPRING (L), TORSION 55 X-4953-605-1 HOLDER (L) ASSY, CASSETTE 56 4-233-094-01 EJECT (L), BUTTON 57 4-900-888-01 EJECT (LEVER-L) 58 3-019-456-11 SCREW, STEP 59 4-951-620-01 SCREW (2.6X8), +BVTP 60 4-900-889-01 EJECT (LEVER-R) 61 4-215-062-01 DAMPER 62 1-680-719-11 TC-PANEL-A DECK BOARD 63 1-680-721-11 TC-SUB PANEL-A BOARD 64 1-680-722-11 TC-SUB PANEL-B BOARD 65 1-680-720-11 TC-PANEL-B DECK BOARD 66 4-233-095-01 EJECT (R), BUTTON 58 59 59 58 60 57 61 61 59 59 64 59 59 65 66 51 52 53 54 55 56 62 63 not supplied #2 TCM-230AWR41/230MWR41 #2 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 23 TC-S3 701 3-016-574-11 SPRING (HEAD), TENSION 702 3-016-565-01 BASE (PINCH LEVER REV) 703 3-016-564-01 BASE (PINCH LEVER FWD) 704 X-3374-156-4 PINCH LEVER (REV) ASSY 705 X-3374-155-4 PINCH LEVER (FWD) ASSY 706 4-229-083-01 SPRING (CASSETTE), LEAF 707 4-227-872-11 SCREW (+PTT 2X4), GROUND POINT 708 1-676-220-11 HEAD (A) BOARD Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 8-3. TAPE MECHANISM DECK SECTION-1 (TCM-230AWR41/230MWR41) 701 701 702 702 703 703 705 705 704 706 706 704 HRPE901 HP901 Note: Two different types of tape mechanism are used depending on models. They maintain compatibility as an entire mechanism even though there are some different parts are used. 710 708 707 707 709 713 PM901 PM902 713 709 1-676-221-11 HEAD (B) BOARD 710 A-2007-838-A LEAF SW BOARD, COMPLETE 713 3-016-566-01 SLIDER, REVERSE HP901 A-2004-771-A BASE (A) ASSY, HEAD HRPE901A-2004-772-A BASE (B) ASSY, HEAD PM901 1-454-887-32 SOLENOID, PLUNGER PM902 1-454-887-32 SOLENOID, PLUNGER www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 24 TC-S3 Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 8-4. TAPE MECHANISM DECK SECTION-2 (TCM-230AWR41/230MWR41) 751 751 752 755 753 754 757 766 767 765 757 763 M901 not supplied not supplied #6 #7 #7 756 762 not supplied 764 751 3-041-946-01 BELT (CAPSTAN B) 752 4-227-239-01 BELT (CAPSTAN C) 753 X-3378-042-1 FLYWHEEL (B-FWD) ASSY 754 X-3378-043-1 FLYWHEEL (B-REV) ASSY 755 X-3378-040-1 FLYWHEEL (A-FWD) ASSY 756 X-3378-041-1 FLYWHEEL (A-REV) ASSY 757 3-041-947-01 BELT (FR) 762 3-318-203-62 SCREW (B1.7X4), TAPPING 763 3-019-208-01 WASHER, STOPPER 764 3-040-580-11 PULLEY (TENSION) 765 4-228-450-11 SPRING (REVERSE SLIDER), TORSION 766 A-2004-793-A CHASSIS (A) ASSY, SUB 767 A-2004-794-A CHASSIS (B) ASSY, SUB M901 X-3378-241-1 MOTOR ASSY (CAPSTAN) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 25 TC-S3 SECTION 9 ELECTRICAL PARTS LIST Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark HEAD (A) HEAD (B) LEAF SW MAIN 1-676-220-11 HEAD (A) BOARD ************** < CONNECTOR > * CN1 1-564-719-11 PIN, CONNECTOR (SMALL TYPE) 3P ************************************************************** 1-676-221-11 HEAD (B) BOARD ************** < CONNECTOR > CN2 1-564-722-11 PIN, CONNECTOR (SMALL TYPE) 6P ************************************************************** A-2007-838-A LEAF SW BOARD, COMPLETE ************************ < CAPACITOR > C1001 1-107-716-11 ELECT 33uF 20% 10V < CONNECTOR > CN1001 1-568-860-21 SOCKET, CONNECTOR 17P < DIODE > D1001 8-719-911-19 DIODE 1SS133T-72 D1002 8-719-911-19 DIODE 1SS133T-72 < PHOTO INTERRUPTER > IC1001 8-749-014-38 PHOTO INTERRUPTER SG-264 IC1002 8-749-014-38 PHOTO INTERRUPTER SG-264 < TRANSISTOR > Q1001 8-729-029-56 TRANSISTOR DTA144ESA-TP < RESISTOR > R907 1-247-879-11 CARBON 100K 5% 1/4W R1001 1-249-409-11 CARBON 220 5% 1/4W R1002 1-249-409-11 CARBON 220 5% 1/4W R1003 1-249-414-11 CARBON 560 5% 1/4W R1004 1-247-834-11 CARBON 1.3K 5% 1/4W R1005 1-247-818-11 CARBON 300 5% 1/4W R1006 1-247-864-11 CARBON 24K 5% 1/4W R1007 1-247-780-00 CARBON 7.5 5% 1/4W NOTE: • Due to standardization, replacements in the parts list may be different from the parts speci- fied in the diagrams or the components used on the set. • -XX and -X mean standardized parts, so they may have some difference from the original one. • RESISTORS All resistors are in ohms. METAL: Metal-film resistor. METAL OXIDE: Metal oxide-film resistor. F: nonflammable • Items marked “*” are not stocked since they are seldom required for routine service. Some delay should be anticipated when order- ing these items. • SEMICONDUCTORS In each case, u: µ, for example: uA. . : µA. . uPA. . : µPA. . uPB. . : µPB. . uPC. . : µPC. . uPD. . : µPD. . • CAPACITORS uF: µF • COILS uH: µH The components identified by mark 0 or dotted line with mark 0 are critical for safety. Replace only with part number specified. When indicating parts by reference number, please include the board. R1008 1-249-417-11 CARBON 1K 5% 1/4W < VARIABLE RESISTOR > RV1001 1-241-785-11 RES, ADJ, CARBON 10K RV1002 1-241-785-11 RES, ADJ, CARBON 10K < SWITCH > S1001 1-570-953-11 SWITCH, PUSH (1 KEY) (A PLAY) S1002 1-570-953-11 SWITCH, PUSH (1 KEY) (B PLAY) S1003 1-771-333-11 SWITCH, LEAF (A.HALF) S1004 1-771-205-11 SWITCH, LEAF (A.120/70) S1005 1-771-205-11 SWITCH, LEAF (REC.A) S1006 1-771-333-11 SWITCH, LEAF (B.HALF) S1008 1-771-205-11 SWITCH, LEAF (B.120/70) S1009 1-771-205-11 SWITCH, LEAF (REC.B) ************************************************************** A-2007-873-A MAIN BOARD, COMPLETE (EXCEPT TH) A-4725-734-A MAIN BOARD, COMPLETE (TH) ********************* 7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S < CAPACITOR > C301 1-126-960-11 ELECT 1uF 20% 50V C302 1-130-479-00 MYLAR 0.0047uF 5% 50V C303 1-136-165-00 FILM 0.1uF 5% 50V C304 1-136-165-00 FILM 0.1uF 5% 50V C305 1-126-959-11 ELECT 0.47uF 20% 50V C306 1-126-960-11 ELECT 1uF 20% 50V C307 1-126-960-11 ELECT 1uF 20% 50V C308 1-126-964-11 ELECT 10uF 20% 50V C309 1-137-194-11 FILM 0.47uF 5% 50V C310 1-162-290-31 CERAMIC 470PF 10% 50V C311 1-126-964-11 ELECT 10uF 20% 50V C312 1-126-959-11 ELECT 0.47uF 20% 50V C313 1-162-294-31 CERAMIC 0.001uF 10% 50V C314 1-126-964-11 ELECT 10uF 20% 50V C315 1-126-963-11 ELECT 4.7uF 20% 50V C316 1-126-933-11 ELECT 100uF 20% 16V C317 1-104-665-11 ELECT 100uF 20% 10V C318 1-126-964-11 ELECT 10uF 20% 50V C319 1-126-961-11 ELECT 2.2uF 20% 50V C320 1-126-961-11 ELECT 2.2uF 20% 50V • Abbreviation TH : Thailand model www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 26 TC-S3 C321 1-162-289-31 CERAMIC 390PF 10% 50V C322 1-162-282-31 CERAMIC 100PF 10% 50V C323 1-136-157-00 FILM 0.022uF 5% 50V C324 1-126-933-11 ELECT 100uF 20% 16V C326 1-162-289-31 CERAMIC 390PF 10% 50V C327 1-104-665-11 ELECT 100uF 20% 10V C328 1-162-282-31 CERAMIC 100PF 10% 50V C329 1-136-153-00 FILM 0.01uF 5% 50V C330 1-126-933-11 ELECT 100uF 20% 16V C332 1-162-283-31 CERAMIC 120PF 10% 50V C333 1-162-288-31 CERAMIC 330PF 10% 50V C334 1-162-209-31 CERAMIC 27PF 5% 50V C335 1-137-150-11 MYLAR 0.01uF 5% 100V C336 1-126-961-11 ELECT 2.2uF 20% 50V C337 1-136-155-00 FILM 0.015uF 5% 50V C338 1-130-481-00 MYLAR 0.0068uF 5% 50V C339 1-130-481-00 MYLAR 0.0068uF 5% 50V C340 1-136-156-00 FILM 0.018uF 5% 50V C341 1-126-960-11 ELECT 1uF 20% 50V C342 1-104-660-11 ELECT 47uF 20% 16V C343 1-164-159-11 CERAMIC 0.1uF 50V C344 1-164-159-11 CERAMIC 0.1uF 50V C345 1-164-159-11 CERAMIC 0.1uF 50V C346 1-164-159-11 CERAMIC 0.1uF 50V C347 1-126-964-11 ELECT 10uF 20% 50V C348 1-164-159-11 CERAMIC 0.1uF 50V C349 1-126-964-11 ELECT 10uF 20% 50V C350 1-126-964-11 ELECT 10uF 20% 50V C351 1-126-960-11 ELECT 1uF 20% 50V C352 1-130-479-00 MYLAR 0.0047uF 5% 50V C353 1-136-165-00 FILM 0.1uF 5% 50V C354 1-136-165-00 FILM 0.1uF 5% 50V C355 1-126-959-11 ELECT 0.47uF 20% 50V C356 1-126-960-11 ELECT 1uF 20% 50V C357 1-126-960-11 ELECT 1uF 20% 50V C358 1-126-964-11 ELECT 10uF 20% 50V C359 1-137-194-11 FILM 0.47uF 5% 50V C360 1-162-290-31 CERAMIC 470PF 10% 50V C362 1-130-479-00 MYLAR 0.0047uF 5% 50V C363 1-130-479-00 MYLAR 0.0047uF 5% 50V C367 1-162-294-31 CERAMIC 0.001uF 10% 50V C368 1-126-964-11 ELECT 10uF 20% 50V C369 1-126-961-11 ELECT 2.2uF 20% 50V C370 1-126-961-11 ELECT 2.2uF 20% 50V C371 1-162-289-31 CERAMIC 390PF 10% 50V C372 1-162-282-31 CERAMIC 100PF 10% 50V C373 1-136-157-00 FILM 0.022uF 5% 50V C374 1-126-933-11 ELECT 100uF 20% 16V C376 1-162-289-31 CERAMIC 390PF 10% 50V C377 1-104-665-11 ELECT 100uF 20% 10V C378 1-162-282-31 CERAMIC 100PF 10% 50V C379 1-136-153-00 FILM 0.01uF 5% 50V C380 1-126-933-11 ELECT 100uF 20% 16V C382 1-162-283-31 CERAMIC 120PF 10% 50V C383 1-162-288-31 CERAMIC 330PF 10% 50V C384 1-162-209-31 CERAMIC 27PF 5% 50V C385 1-104-665-11 ELECT 100uF 20% 10V C386 1-104-665-11 ELECT 100uF 20% 10V C388 1-126-964-11 ELECT 10uF 20% 50V C389 1-126-935-11 ELECT 470uF 20% 16V C390 1-126-964-11 ELECT 10uF 20% 50V C391 1-126-935-11 ELECT 470uF 20% 16V C394 1-126-964-11 ELECT 10uF 20% 50V C395 1-126-964-11 ELECT 10uF 20% 50V C396 1-162-282-31 CERAMIC 100PF 10% 50V C397 1-162-282-31 CERAMIC 100PF 10% 50V C398 1-162-282-31 CERAMIC 100PF 10% 50V C399 1-162-282-31 CERAMIC 100PF 10% 50V C414 1-126-964-11 ELECT 10uF 20% 50V C415 1-126-935-11 ELECT 470uF 20% 10V C417 1-164-159-11 CERAMIC 0.1uF 50V C418 1-164-159-11 CERAMIC 0.1uF 50V < CONNECTOR > * CN308 1-566-856-11 SOCKET, CONNECTOR 5P (SYSTEM CONTROL 4) CN309 1-794-569-11 PIN, CONNECTOR 5P (SYSTEM CONTROL 5) CN310 1-580-176-11 PIN, CONNECTOR 10P (SYSTEM CONTROL 5) CN311 1-784-778-11 CONNECTOR, FFC 17P * CN314 1-568-934-11 PIN, CONNECTOR 7P < DIODE > D306 8-719-024-99 DIODE 11ES2-NTA2B (EXCEPT TH) D306 8-719-200-82 DIODE 11ES2-NTA1B (TH) D307 8-719-024-99 DIODE 11ES2-NTA2B (EXCEPT TH) D307 8-719-200-82 DIODE 11ES2-NTA1B (TH) D308 8-719-024-99 DIODE 11ES2-NTA2B (EXCEPT TH) D308 8-719-200-82 DIODE 11ES2-NTA1B (TH) D309 8-719-024-99 DIODE 11ES2-NTA2B (EXCEPT TH) D309 8-719-200-82 DIODE 11ES2-NTA1B (TH) < GROUND TERMINAL> * EPT300 1-537-738-21 TERMINAL, EARTH * EPT302 1-537-738-21 TERMINAL, EARTH < IC > IC301 8-759-652-02 IC HA12226F IC302 8-759-143-54 IC uPC1330HA IC303 8-759-710-59 IC NJM4580D-D IC304 8-759-710-59 IC NJM4580D-D IC310 6-800-467-01 IC PT8300-S IC311 6-800-467-01 IC PT8300-S IC320 8-759-394-35 IC BA12T IC321 8-759-701-59 IC NJM7809FA < COIL > L301 1-410-780-11 INDUCTOR 27uH L302 1-414-193-41 INDUCTOR 220uH L303 1-414-193-41 INDUCTOR 220uH L351 1-410-780-11 INDUCTOR 27uH < TRANSISTOR > Q301 8-729-801-93 TRANSISTOR 2SD1387-34-TP Q302 8-729-142-46 TRANSISTOR 2SC2001TP-LK Q303 8-729-142-46 TRANSISTOR 2SC2001TP-LK MAIN www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 27 TC-S3 Q304 8-729-422-57 TRANSISTOR BN1A4M-TP Q305 8-729-900-80 TRANSISTOR BA1A4M-TP Q310 8-729-119-78 TRANSISTOR 2SC2785TP-HFE Q391 8-729-140-04 TRANSISTOR 2SB1116-TP-LK Q392 8-729-900-80 TRANSISTOR BA1A4M-TP Q393 8-729-140-04 TRANSISTOR 2SB1116-TP-LK Q394 8-729-900-80 TRANSISTOR BA1A4M-TP Q395 8-729-900-80 TRANSISTOR BA1A4M-TP Q396 8-729-801-93 TRANSISTOR 2SD1387-34-TP Q400 8-729-142-46 TRANSISTOR 2SC2001TP-LK < RESISTOR > R300 1-249-433-11 CARBON 22K 5% 1/4W R301 1-249-421-11 CARBON 2.2K 5% 1/4W R302 1-247-807-31 CARBON 100 5% 1/4W R303 1-247-807-31 CARBON 100 5% 1/4W R304 1-249-427-11 CARBON 6.8K 5% 1/4W R305 1-249-429-11 CARBON 10K 5% 1/4W R306 1-249-430-11 CARBON 12K 5% 1/4W R307 1-247-843-11 CARBON 3.3K 5% 1/4W R308 1-249-433-11 CARBON 22K 5% 1/4W R309 1-247-903-00 CARBON 1M 5% 1/4W R310 1-247-884-11 CARBON 160K 5% 1/4W R311 1-249-441-11 CARBON 100K 5% 1/4W R313 1-249-429-11 CARBON 10K 5% 1/4W R314 1-249-435-11 CARBON 33K 5% 1/4W R315 1-249-429-11 CARBON 10K 5% 1/4W R316 1-249-429-11 CARBON 10K 5% 1/4W R317 1-247-893-11 CARBON 390K 5% 1/4W R318 1-249-418-11 CARBON 1.2K 5% 1/4W R319 1-249-425-11 CARBON 4.7K 5% 1/4W R321 1-249-430-11 CARBON 12K 5% 1/4W R322 1-249-437-11 CARBON 47K 5% 1/4W R323 1-249-425-11 CARBON 4.7K 5% 1/4W R324 1-249-429-11 CARBON 10K 5% 1/4W R325 1-249-437-11 CARBON 47K 5% 1/4W R327 1-249-425-11 CARBON 4.7K 5% 1/4W R328 1-249-437-11 CARBON 47K 5% 1/4W R330 1-247-881-00 CARBON 120K 5% 1/4W R331 1-247-807-31 CARBON 100 5% 1/4W R332 1-249-426-11 CARBON 5.6K 5% 1/4W R333 1-247-882-11 CARBON 130K 5% 1/4W R334 1-249-409-11 CARBON 220 5% 1/4W R335 1-247-881-00 CARBON 120K 5% 1/4W R336 1-249-409-11 CARBON 220 5% 1/4W R337 1-249-433-11 CARBON 22K 5% 1/4W R338 1-249-430-11 CARBON 12K 5% 1/4W R339 1-247-889-00 CARBON 270K 5% 1/4W R340 1-249-409-11 CARBON 220 5% 1/4W R341 1-249-430-11 CARBON 12K 5% 1/4W 0R342 1-212-851-00 FUSIBLE 5.6 5% 1/4W F 0R343 1-212-851-00 FUSIBLE 5.6 5% 1/4W F R344 1-249-432-11 CARBON 18K 5% 1/4W R345 1-249-432-11 CARBON 18K 5% 1/4W R346 1-249-426-11 CARBON 5.6K 5% 1/4W R347 1-249-433-11 CARBON 22K 5% 1/4W R348 1-249-409-11 CARBON 220 5% 1/4W R349 1-249-425-11 CARBON 4.7K 5% 1/4W R350 1-249-433-11 CARBON 22K 5% 1/4W R351 1-249-421-11 CARBON 2.2K 5% 1/4W R354 1-249-427-11 CARBON 6.8K 5% 1/4W R355 1-249-429-11 CARBON 10K 5% 1/4W R356 1-249-430-11 CARBON 12K 5% 1/4W R357 1-247-843-11 CARBON 3.3K 5% 1/4W R358 1-249-435-11 CARBON 33K 5% 1/4W R359 1-249-417-11 CARBON 1K 5% 1/4W R360 1-249-417-11 CARBON 1K 5% 1/4W R361 1-249-417-11 CARBON 1K 5% 1/4W R362 1-249-417-11 CARBON 1K 5% 1/4W R363 1-249-437-11 CARBON 47K 5% 1/4W R364 1-249-417-11 CARBON 1K 5% 1/4W R367 1-249-417-11 CARBON 1K 5% 1/4W R368 1-249-418-11 CARBON 1.2K 5% 1/4W R369 1-249-413-11 CARBON 470 5% 1/4W R370 1-247-881-00 CARBON 120K 5% 1/4W R371 1-247-807-31 CARBON 100 5% 1/4W R372 1-249-426-11 CARBON 5.6K 5% 1/4W R373 1-247-882-11 CARBON 130K 5% 1/4W R375 1-247-881-00 CARBON 120K 5% 1/4W R376 1-249-409-11 CARBON 220 5% 1/4W R377 1-249-433-11 CARBON 22K 5% 1/4W R378 1-249-430-11 CARBON 12K 5% 1/4W R379 1-247-889-00 CARBON 270K 5% 1/4W R386 1-249-410-11 CARBON 270 5% 1/4W R402 1-249-419-11 CARBON 1.5K 5% 1/4W R403 1-249-416-11 CARBON 820 5% 1/4W R404 1-249-419-11 CARBON 1.5K 5% 1/4W R405 1-249-416-11 CARBON 820 5% 1/4W R406 1-247-807-31 CARBON 100 5% 1/4W R407 1-247-807-31 CARBON 100 5% 1/4W R408 1-247-807-31 CARBON 100 5% 1/4W R409 1-247-807-31 CARBON 100 5% 1/4W R412 1-247-807-31 CARBON 100 5% 1/4W R413 1-247-807-31 CARBON 100 5% 1/4W R414 1-247-807-31 CARBON 100 5% 1/4W R415 1-247-807-31 CARBON 100 5% 1/4W R416 1-247-807-31 CARBON 100 5% 1/4W R417 1-247-807-31 CARBON 100 5% 1/4W R418 1-249-414-11 CARBON 560 5% 1/4W R419 1-249-417-11 CARBON 1K 5% 1/4W R420 1-249-409-11 CARBON 220 5% 1/4W R421 1-249-409-11 CARBON 220 5% 1/4W R422 1-249-409-11 CARBON 220 5% 1/4W R423 1-249-409-11 CARBON 220 5% 1/4W < VARIABLE RESISTOR > RV301 1-241-764-11 RES, ADJ, CARBON 10K RV302 1-241-762-11 RES, ADJ, CARBON 2.2K RV303 1-241-762-11 RES, ADJ, CARBON 2.2K RV304 1-241-768-11 RES, ADJ, CARBON 220K RV351 1-241-764-11 RES, ADJ, CARBON 10K RV354 1-241-768-11 RES, ADJ, CARBON 220K MAIN The components identified by mark 0 or dotted line with mark 0 are critical for safety. Replace only with part number specified. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 28 TC-S3 < TRANSFORMER > T301 1-423-980-11 TRANSFORMER, BIAS OSCILLATION ************************************************************** 1-680-719-11 TC-PANEL-A DECK BOARD ********************* < LED > D300 8-719-058-03 LED SEL5423E-TP15 (N) D301 8-719-058-03 LED SEL5423E-TP15 (n) < RESISTOR > R398 1-249-429-11 CARBON 10K 5% 1/4W R399 1-249-431-11 CARBON 15K 5% 1/4W R400 1-249-434-11 CARBON 27K 5% 1/4W R401 1-249-438-11 CARBON 56K 5% 1/4W < SWITCH > S312 1-771-410-21 SWITCH, TACTILE (x) S313 1-771-410-21 SWITCH, TACTILE (n) S314 1-771-410-21 SWITCH, TACTILE (N) S315 1-771-410-21 SWITCH, TACTILE (. m) S316 1-771-410-21 SWITCH, TACTILE (M >) ************************************************************** 1-680-720-11 TC-PANEL-B DECK BOARD ********************* < LED > D302 8-719-058-03 LED SEL5423E-TP15 (N) D303 8-719-058-03 LED SEL5423E-TP15 (n) < RESISTOR > R387 1-249-411-11 CARBON 330 5% 1/4W R388 1-249-413-11 CARBON 470 5% 1/4W R389 1-249-414-11 CARBON 560 5% 1/4W R390 1-249-415-11 CARBON 680 5% 1/4W < SWITCH > S301 1-771-410-21 SWITCH, TACTILE (M >) S302 1-771-410-21 SWITCH, TACTILE (. m) S303 1-771-410-21 SWITCH, TACTILE (N) S304 1-771-410-21 SWITCH, TACTILE (n) S305 1-771-410-21 SWITCH, TACTILE (x) ************************************************************** 1-680-721-11 TC-SUB PANEL-A BOARD ******************** < RESISTOR > R395 1-247-843-11 CARBON 3.3K 5% 1/4W R396 1-249-425-11 CARBON 4.7K 5% 1/4W R397 1-249-427-11 CARBON 6.8K 5% 1/4W < SWITCH > S310 1-771-410-21 SWITCH, TACTILE (DOLBY NR) S311 1-771-410-21 SWITCH, TACTILE (DIRECTION) ************************************************************** 1-680-722-11 TC-SUB PANEL-B BOARD ********************* < RESISTOR > R391 1-249-417-11 CARBON 1K 5% 1/4W R392 1-249-418-11 CARBON 1.2K 5% 1/4W R393 1-249-420-11 CARBON 1.8K 5% 1/4W R394 1-249-422-11 CARBON 2.7K 5% 1/4W < SWITCH > S306 1-771-410-21 SWITCH, TACTILE (REC PAUSE/START) S307 1-771-410-21 SWITCH, TACTILE (CD SYNC) S308 1-771-410-21 SWITCH, TACTILE (HI-DUB) S309 1-771-410-21 SWITCH, TACTILE (EDIT) ************************************************************** MISCELLANEOUS ************** 2 1-773-048-11 WIRE (FLAT TYPE) (17 CORE) 6 1-757-632-11 CORD (WITH CONNECTOR) 15P HP901 A-2004-771-A BASE (A) ASSY, HEAD HRPE901A-2004-772-A BASE (B) ASSY, HEAD M901 X-3378-241-1 MOTOR ASSY (CAPSTAN) PM901 1-454-887-32 SOLENOID, PLUNGER PM902 1-454-887-32 SOLENOID, PLUNGER ************************************************************ ************** HARDWARE LIST ************** #1 7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S #2 7-685-853-04 SCREW +BVTT 2X6 (S) #3 7-685-871-01 SCREW +BVTT 3X6 (S) #6 7-628-254-05 SCREW +PS 2.6X5 #7 7-623-921-01 RING, RETAINING, CAPSTAN MAIN TC-PANEL-A DECK TC-PANEL-B DECK TC-SUB PANEL-A TC-SUB PANEL-B www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 29 TC-S3 MEMO www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com TC-S3 REVISION HISTORY Clicking the version allows you to jump to the revised page. Also, clicking the version at the upper right on the revised page allows you to jump to the next revised page. Ver. Date Description of Revision 1.0 2001.04 New www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com
