US Model XP-ZV71/ZV71C Canadian Model XP-ZV77 AEP Model XP-ZV77/ZV77D UK Model XP-ZV77 E Model XP-ZV77/ZV77C/ZV77D Australian Model XP-ZV77 Chinese Model XP-ZV77D SERVICE MANUAL PORTABLE CD PLAYER Sony Corporation Personal Audio Company Published by Sony Engineering Corporation 9-877-193-04 2003L16-1 © 2003.12 SPECIFICATIONS Ver 1.3 2003. 12 Photo : XP-ZV77 System Compact disc digital audio system Laser diode properties Material: GaAlAs Wavelength: λ = 780 nm Emission duration: Continuous Laser output: Less than 44.6 µW (This output is the value measured at a distance of 200 mm from the objective lens surface on the optical pick-up block with 7 mm aperture.) D-A conversion 1bit DAC Frequency response 20 – 20 000 Hz dB (measured by JEITA CP- 307) Power requirements • Two Ni-MH rechargeable batteries (size AA, 700 mAh): 2.4 V DC • Two LR6 (size AA) batteries: 3 V DC • AC power adaptor (DC IN 4.5 V jack): 120 V, 60 Hz –2 +1 Battery life* (approx. hours) (When you use the CD player on a flat and stable surface.) Playing time varies depending on how the CD player is used. Using two Sony alkaline batteries LR6 (SG) (produced in Japan) EASS 1 EASS 2 Audio disc 30 26 MP3 disc — 32 * Measured value by the standard of JEITA (Japan electronics and Information Technology Industries Association). Operating temperature 5˚C – 35˚C (41˚F – 95˚F) Dimensions (w/h/d) (excluding projecting parts and controls) Approx. 136 × 22.7 × 139 mm (5 3/8 × 29/32 × 5 1/2 in.) Mass (excluding accessories) Approx. 222 g (7.8 oz) Design and specifications are subject to change without notice. XP-ZV71/ZV71C/ZV77/ ZV77C/ZV77D Model Name Using Similar Mechanism D-EJ760 CD Mechanism Type CDM-3325ER Optical Pick-up Name DAX-25E www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 2 XP-ZV71/ZV71C/ZV77/ZV77D Flexible Circuit Board Repairing • Keep the temperature of the soldering iron around 270 ˚C dur- ing repairing. • Do not touch the soldering iron on the same conductor of the circuit board (within 3 times). • Be careful not to apply force on the conductor when soldering or unsoldering. Notes on chip component replacement • Never reuse a disconnected chip component. • Notice that the minus side of a tantalum capacitor may be dam- aged by heat. This appliance is classified as a CLASS 1 LASER product. The CLASS 1 LASER PRODUCT MARKING is located on the rear exterior. CAUTION Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure. On AC power adaptor • Use only the commercially-available AC power adaptor whose rated output is 4.5 V DC, 500 mA. Do not use any other AC power adaptor. It may cause a malfunction. Polarity of the plug TABLE OF CONTENTS 1. SERVICING NOTE ·························································· 3 2. GENERAL ·········································································· 6 3. DISASSEMBLY ································································ 7 3-1. Lower Cabinet Section ···················································· 8 3-2. CD Mechanism Section (CDM-3325ER) ······················· 9 3-3. Cabinet (front) Sub Assy··············································· 10 3-4. Upper Lid Sub Assy ······················································ 11 3-5. MAIN Board ································································· 12 3-6. Optical Pick-up (DAX-25E) ········································· 12 4. ELECTRICAL CHECKING ········································· 13 5. DIAGRAMS ······································································ 14 5-1. Block Diagram ······························································ 15 5-2. Printed Wiring Board – MAIN Board (Side A) – ········ 16 5-3. Printed Wiring Board – MAIN Board (Side B) – ········ 17 5-4. Printed Wiring Board – LID Board –··························· 18 5-5. Schematic Diagram – MAIN Board (1/4) –················· 19 5-6. Schematic Diagram – MAIN Board (2/4), LID Board – ····························· 20 5-7. Schematic Diagram – MAIN Board (3/4) –················· 21 5-8. Schematic Diagram – MAIN Board (4/4) –················· 22 5-9. IC Block Diagrams ······················································· 23 5-10. IC Pin Function Descriptions ······································ 24 6. EXPLODED VIEWS 6-1. Cabinet (upper) Section ················································ 26 6-2. Cabinet (lower) Section ················································ 27 6-3. CD Mechanism Deck Section (CDM-3325ER)············ 28 7. ELECTRICAL PARTS LIST ······································· 29 SAFETY-RELATED COMPONENT WARNING!! COMPONENTS IDENTIFIED BY MARK 0 OR DOTTED LINE WITH MARK 0 ON THE SCHEMATIC DIAGRAMS AND IN THE PARTS LIST ARE CRITICAL TO SAFE OPERATION. REPLACE THESE COMPONENTS WITH SONY PARTS WHOSE PART NUMBERS APPEAR AS SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUBLISHED BY SONY. ATTENTION AU COMPOSANT AYANT RAPPORT À LA SÉCURITÉ! LES COMPOSANTS IDENTIFÉS PAR UNE MARQUE 0 SUR LES DIAGRAMMES SCHÉMATIQUES ET LA LISTE DES PIÈCES SONT CRITIQUES POUR LA SÉCURITÉ DE FONCTIONNEMENT. NE REMPLACER CES COMPOSANTS QUE PAR DES PIÈSES SONY DONT LES NUMÉROS SONT DONNÉS DANS CE MANUEL OU DANS LES SUPPÉMENTS PUBLIÉS PAR SONY. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 3 XP-ZV71/ZV71C/ZV77/ZV77D SECTION 1 SERVICING NOTE The laser diode in the optical pick-up block may suffer electrostatic breakdown because of the potential difference generated by the charged electrostatic load, etc. on clothing and the human body. During repair, pay attention to electrostatic breakdown and also use the procedure in the printed matter which is included in the repair parts. The flexible board is easily damaged and should be handled with care. NOTES ON LASER DIODE EMISSION CHECK The laser beam on this model is concentrated so as to be focused on the disc reflective surface by the objective lens in the optical pick- up block. Therefore, when checking the laser diode emission, observe from more than 30 cm away from the objective lens. BEFORE REPLACING THE OPTICAL PICK-UP BLOCK Please be sure to check thoroughly the parameters as par the “Optical Pick-Up Block Checking Procedures” (Part No.: 9-960-027-11) issued separately before replacing the optical pick-up block. LASER DIODE AND FOCUS SEARCH OPERATION CHECK During normal operation of the equipment, emission of the laser diode is prohibited unless the upper lid is closed while turning ON the S301. (push switch type) The following checking method for the laser diode is operable. • Method: Emission of the laser diode is visually checked. 1. Open the upper lid. 2. With a disc not set, turn on the S301 with a screwdriver having a thin tip as shown in Fig.1. 3. Press the u button. 4. Observing the objective lens, check that the laser diode emits light. When the laser diode does not emit light, automatic power control circuit or optical pickup is faulty. In this operation, the objective lens will move up and down 4 times along with inward motion for the focus search. NOTES ON HANDLING THE OPTICAL PICK-UP BLOCK OR BASE UNIT Fig. 1 Method to push the S301 S301 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 4 XP-ZV71/ZV71C/ZV77/ZV77D SERVICE MODE The following confirmation can be performed when the Service Mode is set. 1. How to set the Service Mode. To set the Service Mode, the following method is available. 1) Confirm the set is not powered on. 2) Confirm the following settings. Solder Land (SL301) ................................ SHORT [HOLD] switch (S309)............................... OFF 3) Short the solder land SL302 (TEST) on the MAIN board. 4) Turn on the main power. – MAIN Board (SIDE A) – IC301 IC501 SL302 (TEST) SL301 (OPEN/CLOSE) 2. Operation when the Service Mode is set. When the Service Mode becomes active, “READING” is displayed and then TOC of the CD is displayed. If CD is not set, “ERROR” is displayed and LCD on the remote control is lit off. 3. Operations by buttons or Rotary control in the Service Mode (Stop status)[TOC is displayed] The following confirmations can be performed by operating buttons(on the CD player or the remote control) or Rotary control. • SLED Movement Mode By pressing the > / . button on the set or the > / . button on the remote control for few seconds, the optical pick-up is moved to outside or inside. (LCD display on the remote control is not changed.) Note : Be sure to keep your eyes apart from the direct emission of the Laser diode. Do not move the optical pick-up over outermost or innermost. • CD-DA/RW Change Over Function By short pressing the > button on the set or the > button on the remote control, the terminal control for gain control is changed and gain for playing of CD-DA or CD-RW is changed over. (LCD display on the remote control is not changed.) • Focus Search Mode By short pressing the [VOL+] button on the set or the [VOL+] button on the remote control, focus search is performed. • Laser ON/OFF Selection Function By short pressing the [VOL-] button on the set or the [VOL-] button on the remote control, laser is switched on or off. Note : Be sure to keep your eyes apart from the direct emission of the Laser diode. • Menu Mode By short pressing the x button on the set or the x button on the remote control, the Menu mode is activated. The menu mode is not used for service, therefore press the x button on the set or the x button on the remote control for short time to exit this mode. (TOC is displayed) 4. Operations by buttons or Rotary control in the Service Mode (Play status) Note : u / x / > / . buttons are available. • Tracking/Sled Servo ON/OFF Change Over Function By short pressing the [VOL+] button on the set or the [VOL+] button on the remote control during play back, Tracking/Sled Servo is switched on or off. (Track number is displayed on the LCD display.) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 5 XP-ZV71/ZV71C/ZV77/ZV77D • Microcomputer Halt Function By short pressing the [VOL-] button on the set or the [VOL-] button on the remote control during play back, the operation of the microcomputer is stopped. After the microcomputer stopped, any key operation or display operation is not performed. Communication with the DSP is not performed. This mode is used only for checking the operation/ function of servo. (LCD on the remote control is lit off) Note : To exit this mode , switch off and then switch on. 5. How to exit the Service Mode 1) Turn off the power. 2) Open the solder land SL302 (TEST) on the MAIN board. Note : The solder should be removed clean. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 6 XP-ZV71/ZV71C/ZV77/ZV77D SECTION 2 GENERAL This section is extracted from instruction manual. Locating the controls 1 P-MODE/ button 2 SOUND button 3 FOLDER SKIP - /+ buttons 4 Display 5 DISPLAY buttons 6 ca /ENTER button* 7 s /OFF/CHARGE button 8 r button 9 t button 0 OPEN switch ! VOL + */- switch @ HOLD switch # \ (headphones) jack $ DC IN 4.5V jack * The button has a tactile dot. % Hand strap hole ^ Battery compartment www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 7 XP-ZV71/ZV71C/ZV77/ZV77D SECTION 3 DISASSEMBLY Note : Disassemble the unit in the order as shown below. LOWER CABINET SECTION CABINET (FRONT) SUB ASSY UPPER LID SUB ASSY CD MECHANISM SECTION (CDM-3325ER) MAIN BOARD SET OPTICAL PICK-UP (DAX-25E) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 8 XP-ZV71/ZV71C/ZV77/ZV77D 3 six screws (B2) 2 two screws (B2) 1 Open the battery lid. 8 flexible board (14P) (CN301) 7 Remove the cabinet (front) assy. upper lid assy in the direction of the arrow. 9 hold knob q; lower cabinet section 4 claw 5 claw 6 claw Note : Follow the disassembly procedure in the numerical order given. 3-1. Lower Cabinet Section www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 9 XP-ZV71/ZV71C/ZV77/ZV77D 3-2. CD Mechanism Section (CDM-3325ER) 5 CD mechanism (CDM-3325ER) 3 flexible board (15P) (CN501) 4 three insulators 1 connector (2P) (CN202) 2 connector (4P) (CN201) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 10 XP-ZV71/ZV71C/ZV77/ZV77D 3-3. Cabinet (front) Sub Assy 7 cabinet (front) assy 5 two claws 6 Remove the upper lid assy in the direction of the arrow. 2 open left spring 4 open right spring 1 Remove the open left spring in the direction of the arrow. upper cabinet 3 Remove the open right spring in the direction of the arrow. upper cabinet upper cabinet www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 11 XP-ZV71/ZV71C/ZV77/ZV77D 3-4. Upper Lid Sub Assy 1 seven screws 2 two claws 3 lid cover 4 flexible board 7 LID board 5 LCD case 8 control main button 9 control sub button q; upper lid sub assy 6 liquid crystal display www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 12 XP-ZV71/ZV71C/ZV77/ZV77D 3-5. MAIN Board 3-6. Optical Pick-up (DAX-25E) 3 MAIN board 2 battery terminal board (relay) 1 Remove the soldering. 1 three screws (B1.7 × 4) 2 gear cover 4 optical pick-up (DAX-25E) chassis 5 three screws (B1.7 × 4) 6 turn table motor assy (spindle) (M901) 3 motor assy (sled) (M902) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 13 XP-ZV71/ZV71C/ZV77/ZV77D SECTION 4 ELECTRICAL CHECKING The CD section adjustments are done automatically in this set. In case of operation check, confirm that RF level. Precautions for Check 1. Perform check in the order given. 2. Use YEDS-18 disc (Part No.: 3-702-101-01) unless otherwise indicated. 3. Power supply voltage requirement : DC4.5 V in DC IN jack. (J101) VOLUME button : Minimum HOLD switch : OFF Checking Location: – MAIN board (SIDE A) – RF Level Check Condition: • Hold the set in horizontal state. Connection: Procedure: 1. Connect the oscilloscope to the test points TP507 (RF) and TP513 (GND) on the MAIN board. 2. Set a disc. (YEDS-18) 3. Press the u button. 4. Check the oscilloscope waveform is as shown below. A good eye pattern means that the diamond shape (◊) in the center of the waveform can be clearly distinguished. RF Signal reference Waveform (Eye Pattern) VOLT/DIV : 100 mV (With the 10:1 probe in use) TIME/DIV : 500 ns To watch the eye pattern, set the oscilloscope to AC range and increase the vertical sensitivity of the oscilloscope for easy watch- ing. 5. Stop revolving of the disc motor by pressing the x button. RF level 0.7 to 0.9 Vp-p IC402 IC302 Q502 TP513 (GND) TP507 (RF) oscilloscope (AC range) + – MAIN board TP507 (RF) TP513 (GND) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 14 XP-ZV71/ZV71C/ZV77/ZV77C/ZV77D SECTION 5 DIAGRAMS Note on Printed Wiring Board • X : parts extracted from the component side. • Y : parts extracted from the conductor side. • : Pattern from the side which enables seeing. (The other layers' patterns are not indicated.) • MAIN board is multi-layer printed board. However, the pat- terns of intermediate-layer have not been included in the dia- gram. Caution: Pattern face side: Parts on the pattern face side seen from (Side A) the pattern face are indicated. Parts face side: Parts on the parts face side seen from (Side B) the parts face are indicated. Note on Schematic Diagram: • All capacitors are in µF unless otherwise noted. pF: µµF 50 WV or less are not indicated except for electrolytics and tantalums. • All resistors are in Ω and 1/4 W or less unless otherwise specified. • % : indicates tolerance. • C : panel designation. • A : B+ Line. • Total current is measured with CD installed. • Power voltage is dc 4.5 V and fed with regulated dc power supply from DC IN jack (J101). • Voltages and waveforms are dc with respect to ground in playback mode. no mark : CD PLAY • Voltages are taken with a VOM (Input impedance 10 MΩ). Voltage variations may be noted due to normal production toler- ances. • Waveforms are taken with a oscilloscope. Voltage variations may be noted due to normal production toler- ances. • Circled numbers refer to waveforms. • Signal path. J : CD PLAY (ANALOG OUT) • Abbreviation CH : Chinese model KR : Korean model HK : Hong Kong model TW : Taiwan model E18 : 100-240V AC Area in E model NOTE FOR PRINTED WIRING BOARDS AND SCHEMATIC DIAGRAMS • WAVEFORMS 800 mVp-p 1 IC501 9 ARF 200mV/DIV, 400ns/DIV 2 IC402 uh X2 1V/DIV, 20ns/DIV 5 IC301 q; MCLK 1V/DIV, 100ns/DIV 3 IC402 ya MCLK 1V/DIV, 400ns/DIV 59ns 236ns 942ns 3.5Vp-p 2.7 Vp-p 3.1 Vp-p 6 IC302 qs OSC2 1V/DIV, 40ns/DIV 118ns 3.0Vp-p 4 IC201 ef SYNC176.4KHZ 1V/DIV, 2us/DIV 5.7us 2.9 Vp-p Note: The components identified by mark 0 or dotted line with mark 0 are critical for safety. Replace only with part number specified. Note: Les composants identifiés par une marque 0 sont critiques pour la sécurité. Ne les remplacer que par une pièce portant le numéro spécifié. Ver 1.2 2003.08 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 15 15 XP-ZV71/ZV71C/ZV77/ZV77D 5-1. Block Diagram • Signal Path : CD RF AMP IC501 RF IN 6 PDE 27 PDF 28 RFSW 43 48 OUTL PDA 32 PDB 30 3 VCC 9 ARF 23 FEOUT 21 TEOUT 25 FBAL 26 TBAL 16 RFDET 15 OFTR 13 BDO 11 3TOUT 24 GCTL 18 PDOWM VCC2 DSP + EASS + MP3 DECODER IC402 RFENV 34 NRFDET 36 FBAL 31 FE 32 TE 33 TBAL 30 OFT 35 BDO 37 TRP 25 TRM 26 FOP 27 FOM 28 TRVP 23 TRVM 24 SPPOL 70 5 VCC VCC2 IN-L 15 IN-R 14 50 OUTR BEEP 17 PWSW 20 MUTSW 19 6 L 8 R HP AMP IC701 /(REMOTE) J701 J702 VCPU ZV77D:AEP,KR ZV77D:AEP,KR EXCEPT ZV77D:AEP,KR 73 TXTD 68 STAT 64 BLKCK 72 TXNCLD 62 MDTA 61 MCLK OSC2 12 OSC1 13 X301 8.46MHz OPTICAL PICK-UP BLOCK (DAX-25E) RF A B E F LD VCC GND PD VR FOCUS C0IL TRACKING COIL MOTOR/COIL DRIVE IC201(1/2) FO3 44 RO3 42 48 46 SLED M902 MOTOR 52 50 M F+ F- T+ T- 58 F2 57 R2 60 59 70 56 LPD 1 LD 2 55 FO2 RO2 F3 R3 BRK FO1 RO1 F1 R1 S+ S- 16 19 14 . 10 15 . . 9 9 12 15 . 19 21 . 8 . 24 25 2 3 . . . 4 NWE 8 NCAS 5 NRAS XWE 4 XCAS 23 XRAS 5 6 7 2 3 . . . A0 A10 A0 A10 D0 D3 16M DRAM IC401 D0 D3 39 DATA 38 CLOCK 36 XRST APC Q502 SPINDLE M901 MOTOR 80 SPCOM 2 U-OUT 4 V-OUT 6 W-OUT VCC2 GAIN UP PU STBY 40 LATCH 34 SYNC 176.4kHz 26 PMG 79 SPUIN 78 SPVIN 77 SPWIN ARF 39 µCOM IC302 24 BEEP 71 STANDBY 70 A-MUTE 44 ISO 45 SI 46 SCK 43 XLT 66 SMCK 42 RW 48 RRST 6 REM 66 K-PLAY SO 15 TSB I/F IC301 1SI 14 SCK 16 XLT 17 MCLK 10 WR 18 RST SO 1SI SCK XLT WR RST SO 1SI SCK XLT WR RST 11 19 TSB LCD DATA 13 VDD0 29 VDD1 VCC2 MDATA 18 MCLK 20 63 MLD MLD 36 69 NRST NDRST 26 74 TXTCLK TXTCLK 38 TXTD 37 STAT 19 BLKCK 31 DQSY 32 58 EXT1 VDET2 47 41 ADPVCC V MON Q401 79 DVDD1 DVDD1-3 21 DVDD2 53 DVDD3 51 AVDD1 VCC1 46 AVDD2 59 IOVDD2 1 DRVDD VCC2 29 IOVDD1 BST SW Q701 BSTN 1 72 DSL2 BSTSW 23 73 DSL1 21 L_SI 23 L_SCL 61 L_CS 60 L_RS 62 L-RST RECHARGEABLE BATTERY 2PCS, 2.4V SWR/H 57 S302 Q204 REG Q205 25 STNG 16 VCC0 20 VCC 62 REGB 61 DCIN 63 DET 68 BATM1 53 VM1 5 SPVCC 1 SPVCC 64 DCIN_S 12 VIN 8 LG POWER CONTROL IC201(2/2) HOLD. ON OFF S656 u S655 x D105 Q101 CHARGE SWITCH D201 D203 Q206 65 CHGB 41 VM3 45 VM23 49 VM12 VCC1 17 VCC1 VCC2 18 VCC2 67 K-STOP D302 Q301 LIQUID CRYSTAL DISPLAY 76 RMC-WU Q303 58 DOOR S301 (OPEN/CLOSE) 56 DOOR2 11 VDD 74 DA/MP3 FUNCTION KEY S303,304,653,654 3 FUNC1 FUNCTION KEY S651,652,657-659 7 FUNC2 37 WAKE UP 74 FG RST SW Q302 VCPU RESET 4 2 IC304 Q203 Q201 DAT 79 CLK 78 LAT 77 SPRST 75 SYNC 29 WU 35 NRST 25 FG BATT1 30 PU-ON 33 GAINUP 40 XREF-ON 34 GCTRL 39 SPOUT 22 72 PWM SP 28 DC IN 4.5V J101 69 BATM2 SWITCHING IC202 VCC BATT1 VCPU 19 2 CHRGIN 4 VDIN CHGMNT 67 VMMNT 66 VMON 5 ACIN GSW 21 SEM 23 BATT1 DVDD1-3 X1 77 X2 76 X401 16.9344MHz VCPU DRY BATTERY SIZE "AA" (IEC DESIGNATION LR6) 2PCS, 3V ZV77D:AEP,KR w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 16 16 XP-ZV71/ZV71C/ZV77/ZV77D 5-2. Printed Wiring Board – MAIN Board (Side A) – Ref. No. Location D102 A-8 D105 B-8 D201 F-9 IC201 E-8 IC301 G-7 IC501 I-6 Q101 C-8 Q205 F-9 • Semiconductor Location C711 C509 C518 C320 C520 L502 L201 C230 L202 R510 R515 R509 R506 R508 R517 C510 R512 R513 R514 CN501 TP517TP516 TP515 TP514 C512 R322 R330 R344 C301 R222 C209 C225 FB704 FB703 C228 C204 C224 C222 L204 CN301 C223 C726 C725 C226 C219 CN202 L203 R340 R213 R214 R205 R229 D201 SL301 (OPEN/CLOSE) S301 (OPEN/CLOSE) C511 C514 C515 R525 C304 R308 C207 C217 C215 C214 C727 CN201 C233 C703 C108 R105 C102 C103 C104 C106 D105 R101 C220 C221 R311 R207 R208 R206 R333 S304 S303 SL302 (TEST) S302 Q205 L206 L210 J701 J702 ZV77D:AEP,KR ZV77D:AEP,KR EXCEPT ZV77D:AEP,KR M901 (SPINDLE MOTOR) M902 (SLED MOTOR) Q101 R103 C107 R102 D102 4 1 2 1 1 15 OPTICAL PICK-UP BLOCK (DAX-25E) HOLD . ON OFF ZV77D:AEP,KR IC201 IC301 IC501 1 13 TO LID BOARD CN651 (Page 18) 14 2 A i i + - VOL 1-688-041- (11) 11 1 2 A B C D E F G H J I 3 4 5 6 7 8 9 10 11 12 13 MAIN BOARD (SIDE A) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 17 17 XP-ZV71/ZV71C/ZV77/ZV77C/ZV77D 5-3. Printed Wiring Board – MAIN Board (Side B) – Ref. No. Location D203 D-5 D301 F-4 D302 H-7 IC202 D-4 IC302 G-6 IC304 F-7 IC401 E-8 IC402 G-9 IC701 G-11 Q201 E-4 Q203 F-4 Q204 D-5 Q206 E-4 Q301 G-4 Q302 F-7 Q303 H-4 Q401 F-9 Q502 I-7 Q701 G-12 • Semiconductor Location TP804 TP405 TP403 TP404 TP402 TP401 TP802 TP803 TP801 R805 C706 C707 C713 C716 C723 R707 R708 R711 C724 C710 C712 C709 R725 R727 R710 R709 R416 R408 R407 R302 R301 R507 R503 R331 R349 R326 R347 R215 R228 R703 R705 R232 R316 R319 R230 R706 R704 R702 C211 C232 C231 C303 C321 Q302 C401 C404 L211 R202 R216 R201 R306 R305 R348 R210 R328 R323 R329 R332 Q701 C708 C720 L402 L401 L501 C722 C419 C411 C403 C412 C416 C415 C421 C714 C728 C715 R720 R415 R417 R413 R414 C422 C420 C410 C405 C307 C302 C522 C506 C523 C505 C513 C319 C507 D302 C309 C314 C234 C305 Q301 Q203 C205 C203 C409 C413 C408 X401 C721 C719 C718 C418 C414 TP505 TP504 TP501 TP502 TP507 (RF) TP510 TP518 TP503 C417 C406 C717 R719 R701 R717R718 R726 R716 R714 R713 R715 R418 R412 R401 R409 R402 R406 Q401 R410 R411 C407 R403 R334 R342 C306 R317 R303 R304 TP315 TP301 TP306 TP313 TP310 TP303 X301 TP314 TP317 R327 C308 C310 SL304 C311 R321 R335R336 C315 C521 C316 C504 C501 C5033 C502 R501 R502 R504 C508 TP513 (GND) TP522 TP520 TP519 Q502 C519 R325 R343 TP521 TP523 TP309 TP311 TP316 Q303 C318 R320 SL305 C216 R221 R227 R226 C218 R223 R219 R220 R211 R217 R338 R310 R309 C313 R337 R346 D301 C202 C213 C212 C210 Q201 R234 C201 Q206 FB706 TP703 TP702 TP707 FB701 FB702 TP704 TP705 TP103 TP105 TP102 TP104 TP101 TP701 TP706 FB705 J101 D203 C236 BT102 Q204 BT101 BT103 R722 C704 R203 TP312 TP320 C312 R315 R307 R313 SL303 TP319 TP318 TP302 B C E ZV77D:AEP,E18,CH,KR,HK,TW ZV77D 4 5 3 1 ZV77D:AEP,KR EXCEPT ZV77D:AEP,KR EXCEPT ZV77D:AEP,KR 3 4 2 1 ZV77D IC401 IC304 IC402 IC302 IC202 IC701 DC IN 3V DRY BATTERY SIZE"AA" (IEC DESGNATION LR6) 2PCS, 3.0V RECHARGEABLE BATTERY 2PCS, 2.4V 1 2 A B C D E F G H J I 3 4 5 6 7 8 9 10 11 12 13 MAIN BOARD (SIDE B) 1-688-041- (11) 11 Ver 1.2 2003.08 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 18 18 XP-ZV71/ZV71C/ZV77/ZV77D 5-4. Printed Wiring Board – LID Board – S653 S654 S655 S656 S657 S658 S659 R607 R608 R617 R611 R609 R606 R618 R601 C608 C612 R603 C607 C614 R602 R616 R615 R614 R613 R612 R619 CN651 C601 C602 C603 C604 C605 C611 R605 R610 CN601 R604 S651 S652 1 18 1 14 LID BOARD 1-688-042- (11) 11 LIQUID CRYSTAL DISPLAY FOLDER SKIP A TO MAIN BOARD CN301 (Page 16) . > OFF/CHG/x ENTER / u DISPLAY SOUND P-MODE / 1 2 A B C D E F G H J I 3 4 5 6 7 8 9 10 11 12 13 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 19 19 XP-ZV71/ZV71C/ZV77/ZV77C/ZV77D 5-5. Schematic Diagram – MAIN Board (1/4) – • See page 14 for Waveforms. • See page 23 for IC Block Diagram. E18, CH, KR, HK, TW E18, CH, KR, HK, TW OTHER MODELS OTHER MODELS TP401 TP402 C408 C410 TP403 TP404 TP405 C419 C412 C413 C420 C407 C722 C720 C718 C717 C714 C719 C721 Q701 C703 C704 C724 C708 TP706 TP801 C415 C418 C411 C403 TP705 TP701 TP802 TP803 TP804 TP703 TP704 TP702 C707 C706 C728 C715 C709 C727 IC402 R406 R407 R408 R409 R410 R411 R412 R413 R402 C422 IC701 R719 R720 R716 R715 R717 R718 R701 R726 R713 R714 C713 C716 FB701 FB705 FB704 C726 C711 R709 R710 R702 R711 R418 R415 R417 Q401 FB703 R708 R725 R805 FB706 C404 R401 C405 C409 C421 C414 C416 C417 R416 R414 C406 C401 C712 R727 C725 R707 R706 R722 R705 TP707 J701 FB702 R703 R704 J702 IC401 X401 L402 L401 R403 C723 C710 0.1 47p 0.1 1000p 0.1 1 1 0.01 0.01 470p 470p 1 1 1 DTC114YUA-T106 10p 10p 0.1 0.1 R OP_G 1000p 0.1 470p 220p L G OPTOUT OP_V OPTDET REM R_V LCD DATA 0.1 0.1 0.22 0.1 0.1 10 MN662791AB 1M 10k 100 0 0 0 47k 47k 47k 22 6.3V TA2120FN(EL) 470 470 10k 10k 47k 47k 22k 22k 10k 10k 22 4V 22 4V 0 0 0 220 4V 100 4V 4.7k 1k 100 4.7 100 470 22k DTC114YUA-T106 0 4.7 0 100k 0 0.1 10 0.1 0.1 47 6.3V 0.022 0.1 0.022 47 10k 22 6.3V 1000p 0.1 0 220 4V 4.7 10k 0 10k R_G MSM51V17400F-10 TK-FS 16.9344MHz 0 0 1 47 4V 2.2 *1 *2 *2 Ver 1.2 2003.08 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 20 20 XP-ZV71/ZV71C/ZV77/ZV77C/ZV77D 5-6. Schematic Diagram – MAIN Board (2/4), LID Board – • See page 14 for Waveform. TP306 TP301 C306 C307 C309 C308 C311 C302 D302 C315 C316 C314 CN301 TP309 TP312 TP311 TP310 TP314 TP315 TP317 C321 C310 TP303 TP313 C312 TP302 C303 TP316 C320 C313 IC302 X301 R342 R321 R334 R306 R308 R301 R302 R303 R304 R328 R333 R331 R332 R335 R336 SL302 R317 R327 SL304 R348 R340 R309 SL303 D301 R320 SL305 S301 R323 R311 SL301 R310 R337 R338 R343 C305 R315 R307 R319 R313 R305 Q301 R329 S304 S303 Q302 R316 IC304 R347 CN651 CN601 R601 TP601 S651 S652 R604 R611 C602 C603 C604 C605 C611 C614 C607 C608 C612 R603 R602 R605 R610 R612 R613 R614 R615 R616 R606 R609 S653 S654 S655 S656 S657 S658 S659 R618 R619 R607 R608 R617 C601 VPP VDD 1000p 1 1000p 1000p 0.01 1000p DAN222-TL 1000p 1000p 0.1 14P 0.1 1000p GND 1000p 0.1 1 0.01 MN101C61G-PA3 8.46MHz 470k 100k 470k 1k 22k 470k 220k 100k 470k 10k 47k 1k 1k 47k 47k 47k 100 VPP 0 100k 1M RST RB521S-30-TE61 100k 100k 1M 1M 100k 1M 100 0.1 1k 4.7k 2.2k 100k 10k DTA114TUA -T106 22k 2SC3326N-TE85L-B PST3617UL 470k 14P 18P 0 100k 47k 0.47 0.47 0.47 0.47 1 0.47 0.47 0.47 10p 10k 22k 22k 100k 100 100 100 100 10 100k 22k 0 0 10k 22k 0 1 *3 ZV77D:E18, CH, KR, HK, TW OTHER MODELS Ver 1.3 2003.12 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 21 21 XP-ZV71/ZV71C/ZV77/ZV77C/ZV77D 5-7. Schematic Diagram – MAIN Board (3/4) – • See page 14 for Waveforms. • See page 23 for IC Block Diagram. OTHER MODELS C225 C207 C218 C209 Q205 C217 C215 C214 C213 C212 C210 C203 C521 C519 C511 C512 C513 C514 C515 C522 C506 C523 C507 C502 C503 TP501 TP502 TP503 TP513 CN201 CN202 C234 C205 C228 C236 C220 Q203 C202 C211 TP515 TP517 TP510 TP505 TP519 TP518 C508 TP504 Q206 L210 C219 C226 R219 R223 R220 R221 R213 R205 R215 R216 R214 R211 R210 R226 R227 Q204 D203 R206 L202 L203 IC501 C520 R501 R502 R503 R507 R504 R508 R509 R510 CN501 R513 R514 C204 R217 R229 R208 L204 C224 R230 R228 R234 R203 R201 R515 R512 R517 C509 R202 C216 L201 R222 C222 C221 C223 C233 R232 R525 C518 Q502 C510 C505 C501 TP514 TP516 R506 TP507 C504 L501 L502 Q201 IC201 L206 C201 R207 D201 1 1000p 10p 2200p 2SC4154TP-1F 4700p 4700p 4700p 0.022 0.022 0.1 1 0.1 1000p 4700p 4700p 0.022 0.022 0.1 2200p 1000p 220p 100p 0.1 0.1 FE TE VC GND 4P 2P 0.1 0.1 1 1 470p DTC114YUA-T106 0.1 1 TOF FOR STB UP LD MD 1000p P_V 2SB1689-T106 220 4V 220 4V 10k 4.7k 10k 1k 10k 220k 22k 470k 220k 22k 0 47k 10k 2SB1237TV2PQR RB160M-30TR 470 AN8399SA-E1 47 6.3V 22k 22k 22k 47k 4.7k 10k 10k 2.2k 15P 2.2k 2.2k 220 6.3V 47k 0 1k 100 4V 0 1k 0 0 100k 10k 10k 0 4V 47 10k 0.022 22k 220 4V 1 100 4V 1 0 10 47 6.3V 2SB1689 -T106 0.1 1000p 1 FOF TOR 2.2k RF 1 0 0 2SC3326N-TE85L-B BH6580KV 0 0 1SS355-17 *4 E18, CH, KR, HK, TW Ver 1.2 2003.08 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 22 22 XP-ZV71/ZV71C/ZV77/ZV77C/ZV77D 5-8. Schematic Diagram – MAIN Board (4/4) – • See page 14 for Waveform. E18, CH, KR, HK, TW C318 C102 C103 IC202 C304 TP102 TP101 TP103 TP104 TP105 C107 C108 C231 C232 R330 R344 BT BT R102 R103 R105 D102 C106 R326 S302 C319 C301 R325 R349 BT101 BT102 BT103 C104 R101 R322 C230 J101 Q101 L211 IC301 Q303 R346 D105 0.47 1 1 QS5U17 0.1 0.1 0.1 1 1 10k 10k 1 2.2 100 RB160M-30TR 22 16V 100k 0.01 0.1 100k 10k 1 100 10 100 4V 2SD1781K-T146-QR 0 CXD751-103R DTC144TU-T106 RB160M-20FTR *5 OTHER MODELS Ver 1.2 2003.08 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 23 XP-ZV71/ZV71C/ZV77/ZV77D 5-9. IC Block Diagrams IC501 AN8399SA-E1 IC701 TA2120FN (EL) BAND GAP 7 5 6 4 3 2 1 26 28 27 29 30 31 32 LPD LD VCC VCC VREF VREF RFN RFOUT RFIN LDRCTL PDA PDC PDB PDD PDF PDE E F E F D B C A A C B D TBAL 14 12 13 11 10 9 8 19 21 20 22 23 24 25 CAGC ARF CEA 3TOUT CBDO BDO COFTR FBAL GCTL FEOUT FEN TEOUT TEN VREF 15 18 OFTR PDOWM 16 17 RFDET GND NRFDET OFTR BDO 3TENV AGC RF_EQ SUBT BCA GCA AMP BCA GCA AMP SUBT BCA GCA AMP BCA GCA AMP + – + – + – 23 18 17 16 15 14 13 2 3 4 5 6 7 8 9 11 12 1 24 BIAS BEEP PW SW MT SW ALC DET ATT SW PWC SW ROUT LOUT BEEP MUTE MUTEC BST PW B PW C BST NF ADD OUT RF IN OCL ROUT VREF LOUT PGND MIXO ALC IN ALC DET ATT LIN RIN GND PWR SW BIAS BIASI BB SW BSTO VCC ADDA ADDB 21 22 PW A ALC ALC 20 19 10 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 24 XP-ZV71/ZV71C/ZV77/ZV77C/ZV77D 5-10. IC Pin Function Descriptions • IC302 MN101C61G-PA3 (SYSTEM CONTROLLER) Pin No. 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 I/O — I I I I I I — — — — O I — — — — O I O O O O O I O O I O I I I O O O O I O O O I O O O I O I O O O Pin Name VREF- CHRGIN FUNC1 VDIN ACIN REM FUNC2 NC VPP VREF+ VDD OSC2 OSC1 VSS XI XO MMOD MDATA STAT MCLK SDO/L_SI P04 BCLK/L_SCL BEEP NRST NDRST XEASS-ON SP SYNC FG BLKCK DQSY PU-ON XREF-ON WU MLD TXTD TXTCK GCTRL GAINUP TX DET RW XLT 1SO SI SCK VDET2 RRST NC CS Description Reference voltage terminal for A/D converter (connected to the ground) Charge voltage A/D input Function key (S303, 304, 653, 654) signal input Battery voltage A/D input AC adaptor detection signal input (HIDCIN detection) Remote commander key A/D input Function key (S651, 652, 657-659) signal input Not used (open) Connected to VDD (supply 5V to VPP at writing the flash memory) Reference voltage terminal for A/D converter (connected to VDD) Power supply terminal (microcomputer) Clock output (8.4672MHz) Clock input (8.4672MHz) Ground terminal (microcomputer) Not used (connected to the ground) Not used (open) Not used (connected to the ground) MDATA output to the DSP (IC402) STAT input from the DSP (IC402) MCLK output to the DSP (IC402) Data output to the liquid crystal display Not used (open) Clock output to the liquid crystal display Beep signal ouput Microcomputer reset signal input “L” : reset Reset signal output to the DSP (IC402) “L” : reset Equalizer selection signal output in case of MP3 “H” : on PWM signal input from the DSP (IC402) Clock (176.4kHz) output to the driver/power controller (IC201) FG pulse input from the driver/power controller (IC201) BLKCK input from the DSP (IC402) DQSY input from the DSP (IC402) Pick-up standby control signal output “H” : on Standby control signal output to the RF amplifier (IC501) “L” : on WAKEUP signal output to the driver/power controller (IC201) “L” : wakeup MLD signal output to the DSP (IC402) CD text data input from the DSP (IC402) Clock for CD text output to the DSP (IC402) Gain control and LD auto power control signal output to the RF amplifier (IC501) “Hi-z” : LD on, “L” : off RF amplifier gain control signal to the optical pick-up “H” : up TX connector detection signal input “H” : connector in Not used (fixed at “L”) TSB RW signal output to the TSB interface (IC301) TSB XLT signal output to the TSB interface (IC301) Serial data output to the TSB interface (IC301) Serial data input to the TSB interface (IC301) Serial clock output to the TSB interface (IC301) VDET2 signal input from the DSP (IC402) Reset signal output to the TSB interface (IC301) Not used (open) Chip select signal output to the EEPROM Not used (open) Ver 1.3 2003.12 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 25 XP-ZV71/ZV71C/ZV77/ZV77D Pin No. 51 52 53 54 55 56 57 58 59 60 61 62 63 64, 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80 I/O O O I I I I I I I O O O I O I I I I O O O O O O O O O O O Pin Name SK DI DO EXTBATT SWDO DOOR2 SWR/H DOOR 2/7 L_RS L_CS L_RST TEST NC K-PLAY K-STOP EEPROM NC A-MUTE STANDBY DSL2 DSL1 DA/MP3 SPRST RMC-WU LAT CLK DAT CHRGLED Description Serial clock output to the EEPROM Not used (open) Serial data output to the EEPROM Not used (open) Serial data input from the EEPROM Not used (open) External battery connection detection signal input “L” : external battery is set Not used (fixed at “H”) TX output changeover signal input (fixed at “L”) Door (open to close) detection signal input “L” just after cancellation of reset : door open to close Hold switch signal input “L” : hold switch on CD door switch detection signal input “L” : door close CHP-2/DHP-7 detection input “L” : CHP-2 (open) Register selection signal output to the liquid crystal display Chip selection signal output to the liquid crystal display Reset signal output to the liquid crystal display Test mode setting input terminal “L” : test mode Not used (open) Play key on the set signal input “H” : play key on Stop key on the set signal input “H” : stop key on EEPROM discrimination signal input terminal Not used (open) Not used (open) Muting control signal output to the headphone amplifier (IC701) “H” : muting on Standby control signal output to the headphone amplifier (IC701) “L” : standby Bass boost control 2 signal output “H” : DSL2 on Bass boost control 1 signal output “H” : DSL1 on DSP output voltage changeover signal output “L” : MP3, “Hi-z” : DA Reset signal output to the driver/power controller (IC201) Remote commander AD line changeover signal output “L” : on Latch signal output to the driver/power controller (IC201) Clock output to the driver/power controller (IC201) Data output to the driver/power controller (IC201) Charge LED control signal output “L” : on Not used (open) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com SECTION 6 EXPLODED VIEWS 26 XP-ZV71/ZV71C/ZV77/ZV77C/ZV77D NOTE: • -XX, -X mean standardized parts, so they may have some differences from the original one. • Items marked “*” are not stocked since they are seldom required for routine service. Some delay should be anticipated when ordering these items. • Accessories and packing materials are given in the last of this parts list. • The mechanical parts with no reference number in the exploded views are not supplied. • Abbreviation AUS : Australian model CH : Chinese model E18 : 100-240V AC Area in E model E33 : 100-240V AC Area in E model (without VS) CND : Canadian model KR : Korean model HK : Hong Kong model TW : Taiwan model The components identified by mark 0 or dotted line with mark 0 are critical for safety. Replace only with part number specified. Les composants identifiés par une marque 0 sont critiques pour la sécurité. Ne les remplacer que par une pièce portant le numéro spécifié. Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks 6-1. Cabinet (upper) Section 1 3-245-862-31 SCREW (B2), TAPPING 2 3-249-069-01 SPRING, TENSION 3 X-3383-301-1 CABINET (FRONT) SUB ASSY (EXCEPT ZV77D:AEP,CH,KR) 3 X-3383-428-1 CABINET (FRONT) SUB ASSY (ZV77D:AEP,CH,KR) 4 3-249-954-01 SPRING,FULL OPEN RIGHT 5 3-249-953-01 SPRING,FULL OPEN LEFT 6 3-249-948-01 BUTTON,CONTROL MAIN 7 3-249-951-01 BUTTON,CONTROL SUB 8 X-3383-302-1 LID SUB ASSY, UPPER (ZV71) 8 X-3383-377-1 LID SUB ASSY, UPPER (ZV71C) 8 X-3383-426-1 LID SUB ASSY, UPPER (ZV77/ZV77D:E18,E33) 8 X-3383-427-1 LID SUB ASSY, UPPER (ZV77D:AEP,CH,KR) 8 X-3383-461-1 LID SUB ASSY, UPPER (ZV77C) 9 1-688-839-11 PWB, FLEXIBLE 10 3-249-956-01 CASE,LCD 11 1-805-178-11 DISPLAY PANEL, LIQUID CRYSTAL * 12 A-3683-496-A LID BOARD COMPLETE 13 3-249-949-01 COVER,LID 14 3-355-424-81 SCREW, TAPPING 15 3-255-466-01 SHEET(COVER,LID),ADH 16 3-254-597-01 CUSHON, CABI not supplied a a cabinet (lower) section 2 1 3 5 6 7 8 9 10 11 4 1 12 13 14 15 16 Ver 1.2 2003.08 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 27 XP-ZV71/ZV71C/ZV77/ZV77C/ZV77D Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks 6-2. Cabinet (lower) Section 51 3-245-331-02 INSULATOR 52 3-254-581-01 CUSHON,COMTACT * 53 A-3683-561-A MAIN BOARD COMPLETE (ZV71/ZV71C/ZV77:CND, E18,E33,AUS/ZV77C) * 53 A-3683-662-A MAIN BOARD COMPLETE (ZV77D:AEP) * 53 A-3683-688-A MAIN BOARD COMPLETE (ZV77:AEP,UK) * 53 A-3683-692-A MAIN BOARD COMPLETE (ZV77D:E18,CH,KR,HK,TW) 54 3-249-065-01 TERMINAL BOARD (-), BATTERY 55 3-249-064-01 TERMINAL BOARD (+), BATTERY 56 3-249-066-01 TERMINAL BOARD (RELAY),BATTERY 57 3-249-054-31 CABINET, LOWER (EXCEPT ZV77D:AEP,CH,KR) 57 3-249-054-41 CABINET, LOWER (ZV77D:AEP,CH,KR) 58 3-249-059-11 KNOB, HOLD 59 3-249-055-11 LID, BATTERY 53 51 51 52 52 54 57 59 58 55 56 not supplied not supplied CD mechanism deck section (CDM-3325ER) Ver 1.2 2003.08 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 28 XP-ZV71/ZV71C/ZV77/ZV77D Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks 6-3. CD Mechanism Deck Section (CDM-3325ER) 101 3-318-203-61 SCREW (B1.7X4), TAPPING 0102 X-3380-950-1 OPTICAL PICK-UP (DAX-25E) 103 3-221-473-01 COVER, GEAR 104 3-221-472-02 CHASSIS 105 3-221-474-01 SPRING, SLED 106 A-3180-967-A FEED ASSY, SCREW 107 3-221-268-01 GEAR (B) 108 3-221-475-01 SHAFT, STANDARD 109 3-222-298-01 RACK 110 3-222-299-01 SPRING, RACK RETAINER 111 3-348-998-31 SCREW (M1.4X2.5), TAPPING, PAN M901 A-3180-965-A MOTOR ASSY, TURN TABLE (SPINDLE) M902 A-3180-966-A MOTOR ASSY, SLED (SLED) 101 108 103 106 105 107 111 109 110 101 104 102 M902 M901 The components identified by mark 0 or dotted line with mark 0 are critical for safety. Replace only with part number specified. Les composants identifiés par une marque 0 sont critiques pour la sécurité. Ne les remplacer que par une pièce portant le numéro spécifié. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 29 SECTION 7 ELECTRICAL PARTS LIST XP-ZV71/ZV71C/ZV77/ZV77C/ZV77D NOTE: • Due to standardization, replacements in the parts list may be different from the parts speci- fied in the diagrams or the components used on the set. • -XX and -X mean standardized parts, so they may have some difference from the original one. • RESISTORS All resistors are in ohms. METAL: Metal-film resistor. METAL OXIDE: Metal oxide-film resistor. F: nonflammable • Items marked “*” are not stocked since they are seldom required for routine service. Some delay should be anticipated when order- ing these items. • SEMICONDUCTORS In each case, u: µ, for example: uA. . : µA. . uPA. . : µPA. . uPB. . : µPB. . uPC. . : µPC. . uPD. . : µPD. . • Abbreviation AUS : Australian model CH : Chinese model E18 : 100-240V AC Area in E model E33 : 100-240V AC Area in E model (without VS) CND: Canadian model KR : Korean model HK : Hong Kong model TW : Taiwan model When indicating parts by reference number, please include the board name. The components identified by mark 0 or dotted line with mark 0 are critical for safety. Replace only with part number specified. Les composants identifiés par une marque 0 sont critiques pour la sécurité. Ne les remplacer que par une pièce portant le numéro spécifié. Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks • CAPACITORS uF: µF • COILS uH: µH * A-3683-496-A LID BOARD, COMPLETE ******************* < CAPACITOR > C601 1-115-156-11 CERAMIC CHIP 1uF 10V C602 1-113-619-11 CERAMIC CHIP 0.47uF 10V C603 1-113-619-11 CERAMIC CHIP 0.47uF 10V C604 1-113-619-11 CERAMIC CHIP 0.47uF 10V C605 1-113-619-11 CERAMIC CHIP 0.47uF 10V C607 1-113-619-11 CERAMIC CHIP 0.47uF 10V C608 1-113-619-11 CERAMIC CHIP 0.47uF 10V C611 1-115-156-11 CERAMIC CHIP 1uF 10V C612 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V C614 1-113-619-11 CERAMIC CHIP 0.47uF 10V < CONNECTOR > CN601 1-816-276-21 CONNECTOR, FPC (ZIF) 18P CN651 1-817-459-11 CONNECTOR, FFC/FPC (ZIF) < RESISTOR > R601 1-216-295-91 SHORT CHIP 0 R602 1-216-837-11 METAL CHIP 22K 5% 1/16W R603 1-216-833-11 METAL CHIP 10K 5% 1/16W R604 1-216-845-11 METAL CHIP 100K 5% 1/16W R605 1-216-837-11 METAL CHIP 22K 5% 1/16W R606 1-216-845-11 METAL CHIP 100K 5% 1/16W R607 1-216-833-11 METAL CHIP 10K 5% 1/16W R608 1-216-837-11 METAL CHIP 22K 5% 1/16W R609 1-216-837-11 METAL CHIP 22K 5% 1/16W R610 1-216-845-11 METAL CHIP 100K 5% 1/16W R611 1-216-841-11 METAL CHIP 47K 5% 1/16W R612 1-216-809-11 METAL CHIP 100 5% 1/16W R613 1-216-809-11 METAL CHIP 100 5% 1/16W R614 1-216-809-11 METAL CHIP 100 5% 1/16W R615 1-216-809-11 METAL CHIP 100 5% 1/16W R616 1-216-797-11 METAL CHIP 10 5% 1/16W R617 1-216-295-91 SHORT CHIP 0 R618 1-216-295-91 SHORT CHIP 0 R619 1-216-295-91 SHORT CHIP 0 < SWITCH > S651 1-771-138-21 SWITCH, KEY BOARD (-) S652 1-771-138-21 SWITCH, KEY BOARD (+) S653 1-771-138-21 SWITCH, KEY BOARD (.) S654 1-771-138-21 SWITCH, KEY BOARD (>) S655 1-771-138-21 SWITCH, KEY BOARD (x) S656 1-771-138-21 SWITCH, KEY BOARD (u) S657 1-771-138-21 SWITCH, KEY BOARD (DISPLAY) S658 1-771-138-21 SWITCH, KEY BOARD (SOUND) S659 1-771-138-21 SWITCH, KEY BOARD ( ) ************************************************************ * A-3683-561-A MAIN BOARD, COMPLETE (ZV71/ZV71C/ZV77:CND,E18,E33,AUS/ZV77C) ************************************* * A-3683-662-A MAIN BOARD, COMPLETE (ZV77D:AEP) ******************************** * A-3683-688-A MAIN BOARD, COMPLETE (ZV77:AEP,UK) ********************************* * A-3683-692-A MAIN BOARD, COMPLETE (ZV77D:E18,CH,KR,HK,TW) ******************************* 3-249-064-01 TERMINAL BOARD (+), BATTERY 3-249-065-01 TERMINAL BOARD (-), BATTERY < CAPACITOR > C102 1-115-156-11 CERAMIC CHIP 1uF 10V C103 1-115-156-11 CERAMIC CHIP 1uF 10V C104 1-115-156-11 CERAMIC CHIP 1uF 10V C106 1-126-395-11 ELECT 22uF 20% 16V C107 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V C108 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V C201 1-165-897-11 TANTAL. CHIP 22uF 20% 10V (EXCEPT ZV77:AEP,UK/ZV77D:E18,CH,KR,HK,TW) C201 1-127-692-11 CERAMIC CHIP 10uF 10.00% 6.3V (ZV77:AEP,UK/ZV77D:E18,CH,KR,HK,TW) C202 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V C203 1-115-156-11 CERAMIC CHIP 1uF 10V C204 1-128-829-91 TANTAL. CHIP 220uF 20% 6.3V C205 1-164-156-11 CERAMIC CHIP 0.1uF 25V C207 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C209 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V C210 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V C211 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V C212 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V C213 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V C214 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V C215 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V MAIN LID Ver 1.2 2003.08 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks 30 XP-ZV71/ZV71C/ZV77/ZV77C/ZV77D C216 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V C217 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V C218 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V C219 1-124-434-00 ELECT 220uF 20.00% 4V C220 1-164-315-11 CERAMIC CHIP 470PF 5.00% 50V C221 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V C222 1-124-434-00 ELECT 220uF 20.00% 4V C223 1-126-209-11 ELECT CHIP 100uF 20.00% 4V C224 1-126-209-11 ELECT CHIP 100uF 20.00% 4V C225 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V C226 1-124-434-00 ELECT 220uF 20.00% 4V C228 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V C230 1-126-209-11 ELECT CHIP 100uF 20.00% 4V C231 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V C232 1-115-156-11 CERAMIC CHIP 1uF 10V C233 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V C234 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V C236 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V C301 1-164-156-11 CERAMIC CHIP 0.1uF 25V (ZV77D) C302 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C303 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V C304 1-164-156-11 CERAMIC CHIP 0.1uF 25V (ZV77D) C305 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V C306 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C307 1-115-156-11 CERAMIC CHIP 1uF 10V C308 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C309 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C310 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C311 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C312 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C313 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C314 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V C315 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C316 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C318 1-117-863-11 CERAMIC CHIP 0.47uF 10.00% 6.3V C319 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C320 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V C321 1-164-156-11 CERAMIC CHIP 0.1uF 25V C401 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C403 1-164-230-11 CERAMIC CHIP 220PF 5.00% 50V C404 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V C405 1-164-156-11 CERAMIC CHIP 0.1uF 25V C406 1-119-750-11 TANTAL. CHIP 22uF 20.00% 6.3V C407 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V C408 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V C409 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V C410 1-162-923-11 CERAMIC CHIP 47PF 5% 50V C411 1-164-315-11 CERAMIC CHIP 470PF 5.00% 50V C412 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C413 1-164-156-11 CERAMIC CHIP 0.1uF 25V C414 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V C415 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C416 1-164-156-11 CERAMIC CHIP 0.1uF 25V C417 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V C418 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V C419 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V C420 1-115-156-11 CERAMIC CHIP 1uF 10V C421 1-100-539-91 TANTAL. CHIP 47uF 20% 6.3V C422 1-119-750-11 TANTAL. CHIP 22uF 20.00% 6.3V C501 1-115-156-11 CERAMIC CHIP 1uF 10V C502 1-164-156-11 CERAMIC CHIP 0.1uF 25V C503 1-164-156-11 CERAMIC CHIP 0.1uF 25V C504 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V C505 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C506 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C507 1-162-927-11 CERAMIC CHIP 100PF 5% 50V C508 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C509 1-131-862-91 TANTAL. CHIP 47uF 20% 4V C510 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V C511 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V C512 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V C513 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V C514 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V C515 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V C518 1-100-539-91 TANTAL. CHIP 47uF 20% 6.3V C519 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C520 1-100-539-91 TANTAL. CHIP 47uF 20% 6.3V C521 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V C522 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V C523 1-164-230-11 CERAMIC CHIP 220PF 5.00% 50V C703 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V C704 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V C706 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V C707 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V C708 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V C709 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V C710 1-125-838-11 CERAMIC CHIP 2.2uF 10% 6.3V C711 1-126-209-11 ELECT CHIP 100uF 20.00% 4V C712 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V C713 1-104-847-11 TANTAL. CHIP 22uF 20.00% 4V C714 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V C715 1-164-156-11 CERAMIC CHIP 0.1uF 25V C716 1-104-847-11 TANTAL. CHIP 22uF 20.00% 4V C717 1-162-962-11 CERAMIC CHIP 470PF 10% 50V C718 1-162-962-11 CERAMIC CHIP 470PF 10% 50V C719 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V C720 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C721 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V C722 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C723 1-131-862-91 TANTAL. CHIP 47uF 20% 4V C724 1-164-156-11 CERAMIC CHIP 0.1uF 25V C725 1-124-434-00 ELECT 220uF 20.00% 4V C726 1-124-434-00 ELECT 220uF 20.00% 4V C727 1-135-259-11 TANTAL. CHIP 10uF 20.00% 6.3V (ZV77D) C728 1-115-467-11 CERAMIC CHIP 0.22uF 10.00% 10V < CONNECTOR > * CN201 1-785-877-21 HOUSING, CONNECTOR 4P CN202 1-784-342-21 HOUSING, CONNECTOR 2P CN301 1-779-331-11 CONNECTOR, FFC/FPC 14P CN501 1-573-355-11 CONNECTOR, FFC/FPC (ZIF) 15P < DIODE > D102 8-719-081-34 DIODE RB160M-30TR D105 6-500-220-11 DIODE RB161M-20FTR D201 8-719-988-61 DIODE 1SS355TE-17 D203 8-719-081-34 DIODE RB160M-30TR D301 8-719-071-34 DIODE RB521S-30-TE61 D302 8-719-989-03 DIODE DAN222-TL MAIN Ver 1.1 2003.06 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks 31 XP-ZV71/ZV71C/ZV77/ZV77C/ZV77D < FERRITE BEAD > FB701 1-216-864-11 METAL CHIP 0 5% 1/16W (ZV77D) FB702 1-216-298-00 METAL CHIP 2.2 5% 1/10W (ZV77D:AEP) FB702 1-400-145-21 INDUCTOR 47uH (ZV77D:E18,CH,KR,HK,TW) FB703 1-500-234-22 FERRITE 0uH FB704 1-500-234-22 FERRITE 0uH FB705 1-500-234-22 FERRITE 0uH FB706 1-216-864-11 METAL CHIP 0 5% 1/16W (ZV77D) < IC > IC201 6-703-034-01 IC BH6580KV IC202 6-550-573-01 TRANSISTOR QS5U17 IC301 8-752-397-55 IC CXD751-103R (ZV77D) IC302 6-802-688-04 IC MN101C61G-PA3 IC304 6-703-959-01 IC PST3617UL IC401 6-700-195-01 IC MSM51V17400F-10TK-FS IC402 6-703-713-01 IC MN662791AB IC501 6-703-626-01 IC AN8399SA-E1 IC701 8-759-681-65 IC TA2120FN(EL) < JACK > J101 1-778-153-51 JACK,DC(POLARITY UNIFIED TYPE) (DC IN 4.5V) J701 1-793-288-23 JACK (i) (ZV77D) J702 1-815-135-42 JACK, HEADPHONE (i) (EXCEPT ZV77D) < COIL > L201 1-469-966-21 INDUCTOR 1uH L202 1-400-145-21 INDUCTOR 47uH L203 1-400-145-21 INDUCTOR 47uH L204 1-419-368-21 INDUCTOR 47uH L206 1-400-416-21 INDUCTOR 0uH L210 1-469-967-21 INDUCTOR 10uH L211 1-400-416-21 INDUCTOR 0uH L401 1-400-417-21 INDUCTOR 0uH L402 1-400-416-21 INDUCTOR 0uH L501 1-400-416-21 INDUCTOR 0uH L502 1-400-416-21 INDUCTOR 0uH < TRANSISTOR > Q101 8-729-921-73 TRANSISTOR 2SD1781K-T146-QR Q201 8-729-202-38 TRANSISTOR 2SC3326N-TE85L-B Q203 8-729-028-99 TRANSISTOR DTC114YUA-T106 Q204 6-550-070-01 TRANSISTOR 2SB1237TV2PQR Q205 8-729-602-21 TRANSISTOR 2SC4154TP-1F Q206 6-550-044-01 TRANSISTOR 2SB1689-T106 Q301 8-729-028-74 TRANSISTOR DTA114TUA-T106 (ZV77D) Q302 8-729-202-38 TRANSISTOR 2SC3326N-TE85L-B Q303 8-729-029-15 TRANSISTOR DTC144TU-T106 Q401 8-729-028-99 TRANSISTOR DTC114YUA-T106 Q502 6-550-044-01 TRANSISTOR 2SB1689-T106 Q701 8-729-028-99 TRANSISTOR DTC114YUA-T106 < RESISTOR > R101 1-216-809-11 METAL CHIP 100 5% 1/16W R102 1-217-671-11 METAL CHIP 1 5% 1/10W R103 1-216-298-00 METAL CHIP 2.2 5% 1/10W R105 1-216-809-11 METAL CHIP 100 5% 1/16W R201 1-216-845-11 METAL CHIP 100K 5% 1/16W R202 1-216-833-11 METAL CHIP 10K 5% 1/16W R203 1-216-864-11 METAL CHIP 0 5% 1/16W R205 1-216-849-11 METAL CHIP 220K 5% 1/16W R206 1-216-817-11 METAL CHIP 470 5% 1/16W R207 1-216-864-11 METAL CHIP 0 5% 1/16W R208 1-216-821-11 METAL CHIP 1K 5% 1/16W R210 1-216-864-11 METAL CHIP 0 5% 1/16W R211 1-218-879-11 METAL CHIP 22K 0.5% 1/10W R213 1-216-833-11 METAL CHIP 10K 5% 1/16W R214 1-216-849-11 METAL CHIP 220K 5% 1/16W R215 1-218-879-11 METAL CHIP 22K 0.5% 1/10W R216 1-218-911-11 METAL CHIP 470K 0.5% 1/10W R217 1-218-887-11 METAL CHIP 47K 0.5% 1/10W R219 1-218-871-11 METAL CHIP 10K 0.5% 1/10W R220 1-218-871-11 METAL CHIP 10K 0.5% 1/10W R221 1-216-821-11 METAL CHIP 1K 5% 1/16W R222 1-216-837-11 METAL CHIP 22K 5% 1/16W R223 1-216-829-11 METAL CHIP 4.7K 5% 1/16W R226 1-216-841-11 METAL CHIP 47K 5% 1/16W R227 1-218-871-11 METAL CHIP 10K 0.5% 1/10W R228 1-216-821-11 METAL CHIP 1K 5% 1/16W R229 1-216-864-11 METAL CHIP 0 5% 1/16W R230 1-216-864-11 METAL CHIP 0 5% 1/16W R232 1-216-864-11 METAL CHIP 0 5% 1/16W R234 1-216-295-91 SHORT CHIP 0 R301 1-218-911-11 METAL CHIP 470K 0.5% 1/10W R302 1-218-903-11 METAL CHIP 220K 0.5% 1/10W R303 1-218-895-11 METAL CHIP 100K 0.5% 1/10W R304 1-218-911-11 METAL CHIP 470K 0.5% 1/10W R305 1-216-833-11 METAL CHIP 10K 5% 1/16W (EXCEPT ZV77D) R305 1-218-871-11 METAL CHIP 10K 0.5% 1/10W (ZV77D) R306 1-216-821-11 METAL CHIP 1K 5% 1/16W R307 1-218-863-11 METAL CHIP 4.7K 0.5% 1/10W R308 1-216-837-11 METAL CHIP 22K 5% 1/16W R309 1-216-857-11 METAL CHIP 1M 5% 1/16W R310 1-216-857-11 METAL CHIP 1M 5% 1/16W R311 1-216-857-11 METAL CHIP 1M 5% 1/16W (ZV77D) R313 1-216-845-11 METAL CHIP 100K 5% 1/16W R315 1-218-847-11 METAL CHIP 1K 0.5% 1/10W R316 1-216-845-11 METAL CHIP 100K 5% 1/16W (EXCEPT ZV77:AEP,UK/ZV77D:E18,CH,KR,HK,TW) R316 1-216-821-11 METAL CHIP 1K 5% 1/16W (ZV77:AEP,UK/ZV77D:E18,CH,KR,HK,TW) R317 1-216-841-11 METAL CHIP 47K 5% 1/16W R319 1-218-855-11 METAL CHIP 2.2K 0.5% 1/10W R320 1-216-845-11 METAL CHIP 100K 5% 1/16W R321 1-216-845-11 METAL CHIP 100K 5% 1/16W MAIN Ver 1.3 2003.12 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks 32 XP-ZV71/ZV71C/ZV77/ZV77C/ZV77D R322 1-216-797-11 METAL CHIP 10 5% 1/16W (ZV77D) R323 1-216-845-11 METAL CHIP 100K 5% 1/16W R325 1-216-845-11 METAL CHIP 100K 5% 1/16W R326 1-216-845-11 METAL CHIP 100K 5% 1/16W R327 1-216-809-11 METAL CHIP 100 5% 1/16W R328 1-216-833-11 METAL CHIP 10K 5% 1/16W R329 1-216-837-11 METAL CHIP 22K 5% 1/16W R330 1-216-833-11 METAL CHIP 10K 5% 1/16W (ZV77D) R331 1-216-821-11 METAL CHIP 1K 5% 1/16W R332 1-216-821-11 METAL CHIP 1K 5% 1/16W R333 1-216-841-11 METAL CHIP 47K 5% 1/16W R334 1-216-853-11 METAL CHIP 470K 5% 1/16W R335 1-216-841-11 METAL CHIP 47K 5% 1/16W R336 1-216-841-11 METAL CHIP 47K 5% 1/16W R337 1-218-895-11 METAL CHIP 100K 0.5% 1/10W R338 1-216-857-11 METAL CHIP 1M 5% 1/16W R340 1-216-845-11 METAL CHIP 100K 5% 1/16W R342 1-216-853-11 METAL CHIP 470K 5% 1/16W R343 1-216-809-11 METAL CHIP 100 5% 1/16W R344 1-216-833-11 METAL CHIP 10K 5% 1/16W (ZV77D) R346 1-216-837-11 METAL CHIP 22K 5% 1/16W (EXCEPT ZV77:AEP,UK/ZV77D:E18,CH,KR,HK,TW) R346 1-216-829-11 METAL CHIP 4.7K 5% 1/16W (ZV77:AEP,UK/ZV77D:E18,CH,KR,HK,TW) R347 1-216-853-11 METAL CHIP 470K 5% 1/16W (EXCEPT ZV77D) R348 1-216-864-11 METAL CHIP 0 5% 1/16W (ZV77D) R349 1-216-833-11 METAL CHIP 10K 5% 1/16W R401 1-216-797-11 METAL CHIP 10 5% 1/16W R402 1-216-841-11 METAL CHIP 47K 5% 1/16W R403 1-218-446-11 METAL CHIP 1 5% 1/10W R406 1-216-857-11 METAL CHIP 1M 5% 1/16W R407 1-216-833-11 METAL CHIP 10K 5% 1/16W R408 1-216-809-11 METAL CHIP 100 5% 1/16W R409 1-216-864-11 METAL CHIP 0 5% 1/16W R410 1-216-864-11 METAL CHIP 0 5% 1/16W R411 1-216-864-11 METAL CHIP 0 5% 1/16W R412 1-216-841-11 METAL CHIP 47K 5% 1/16W R413 1-216-841-11 METAL CHIP 47K 5% 1/16W R414 1-216-833-11 METAL CHIP 10K 5% 1/16W R415 1-216-817-11 METAL CHIP 470 5% 1/16W R416 1-216-805-11 METAL CHIP 47 5% 1/16W R417 1-216-837-11 METAL CHIP 22K 5% 1/16W R418 1-216-809-11 METAL CHIP 100 5% 1/16W R501 1-216-837-11 METAL CHIP 22K 5% 1/16W R502 1-216-837-11 METAL CHIP 22K 5% 1/16W R503 1-216-837-11 METAL CHIP 22K 5% 1/16W R504 1-216-829-11 METAL CHIP 4.7K 5% 1/16W R506 1-216-825-11 METAL CHIP 2.2K 5% 1/16W R507 1-216-841-11 METAL CHIP 47K 5% 1/16W R508 1-216-833-11 METAL CHIP 10K 5% 1/16W R509 1-216-833-11 METAL CHIP 10K 5% 1/16W R510 1-216-825-11 METAL CHIP 2.2K 5% 1/16W R512 1-218-871-11 METAL CHIP 10K 0.5% 1/10W R513 1-216-825-11 METAL CHIP 2.2K 5% 1/16W R514 1-216-825-11 METAL CHIP 2.2K 5% 1/16W R515 1-218-871-11 METAL CHIP 10K 0.5% 1/10W R517 1-216-864-11 METAL CHIP 0 5% 1/16W R525 1-216-797-11 METAL CHIP 10 5% 1/16W R701 1-216-837-11 METAL CHIP 22K 5% 1/16W R702 1-216-809-11 METAL CHIP 100 5% 1/16W (ZV77D) R703 1-216-789-11 METAL CHIP 2.2 5% 1/16W (ZV71/ZV71C/ZV77:CND,E18,E33,AUS/ZV77C) R703 1-216-864-11 METAL CHIP 0 5% 1/16W (ZV77D:E18,CH,KR,HK,TW) R703 1-216-793-11 METAL CHIP 4.7 5% 1/10W (ZV77:AEP,UK/ZV77D:AEP) R704 1-216-789-11 METAL CHIP 2.2 5% 1/16W (ZV71/ZV71C/ZV77:CND,E18,E33,AUS/ZV77C) R704 1-216-864-11 METAL CHIP 0 5% 1/16W (ZV77D:E18,CH,KR,HK,TW) R704 1-216-793-11 METAL CHIP 4.7 5% 1/10W (ZV77:AEP,UK/ZV77D:AEP) R705 1-216-833-11 METAL CHIP 10K 5% 1/16W R706 1-216-833-11 METAL CHIP 10K 5% 1/16W R707 1-216-793-11 METAL CHIP 4.7 5% 1/10W R708 1-216-793-11 METAL CHIP 4.7 5% 1/10W R709 1-216-829-11 METAL CHIP 4.7K 5% 1/16W R710 1-216-821-11 METAL CHIP 1K 5% 1/16W R711 1-216-793-11 METAL CHIP 4.7 5% 1/10W R713 1-216-833-11 METAL CHIP 10K 5% 1/16W R714 1-216-833-11 METAL CHIP 10K 5% 1/16W R715 1-216-833-11 METAL CHIP 10K 5% 1/16W R716 1-216-833-11 METAL CHIP 10K 5% 1/16W R717 1-216-841-11 METAL CHIP 47K 5% 1/16W R718 1-216-841-11 METAL CHIP 47K 5% 1/16W R719 1-216-817-11 METAL CHIP 470 5% 1/16W R720 1-216-817-11 METAL CHIP 470 5% 1/16W R722 1-216-864-11 METAL CHIP 0 5% 1/16W R725 1-216-864-11 METAL CHIP 0 5% 1/16W R726 1-216-837-11 METAL CHIP 22K 5% 1/16W R727 1-216-864-11 METAL CHIP 0 5% 1/16W R805 1-216-845-11 METAL CHIP 100K 5% 1/16W < SWITCH > S301 1-762-805-41 SWITCH, PUSH (1 KEY) S302 1-572-922-11 SWITCH, SLIDE (HOLD.) S303 1-771-248-11 SWITCH, TACTILE (VOL+) S304 1-771-248-11 SWITCH, TACTILE (VOL-) < VIBRATOR > X301 1-795-909-11 VIBRATOR, CERAMIC (SMD) 8.46MHz X401 1-795-561-21 VIBRATOR, CERAMIC 16.9344MHz ************************************************************ MISCELLANEOUS ************* 9 1-688-839-11 PWB, FLEXIBLE 11 1-805-178-11 DISPLAY PANEL, LIQUID CRYSTAL 0102 X-3380-950-1 OPTICAL PICK-UP (DAX-25E) M901 A-3180-965-A MOTOR ASSY, TURN TABLE (SPINDLE) M902 A-3180-966-A MOTOR ASSY, SLED (SLED) MAIN The components identified by mark 0 or dotted line with mark 0 are critical for safety. Replace only with part number specified. Les composants identifiés par une marque 0 sont critiques pour la sécurité. Ne les remplacer que par une pièce portant le numéro spécifié. Ver 1.2 2003.08 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com Ref. No. Part No. Description Remarks 33 XP-ZV71/ZV71C/ZV77/ZV77C/ZV77D ACCESSORIES *********** 1-417-362-11 CONNECTING PACK, CAR (ZV71C,ZV77C) 0 1-477-496-21 ADAPTOR, AC (AC-ES455K) (E33) 0 1-477-497-21 ADAPTOR, AC (AC-ES455K) (ZV77D:KR) 0 1-477-499-21 ADAPTOR, AC (AC-ES455K) (CH) 0 1-477-500-21 ADAPTOR, AC (AC-ES455K) (ZV77:AEP,E18/ZV77D:AEP,E18) 0 1-477-501-21 ADAPTOR, AC (AC-ES455K) (ZV77:UK/ZV77D:HK) 0 1-477-502-21 ADAPTOR, AC (AC-ES455K) (ZV77:CND/ZV77D:TW) 0 1-477-503-21 ADAPTOR, AC (AC-ES455K) (ZV77:AUS) 1-477-744-12 REMOTE COMMANDER (RC-Z1C002) (ZV77D) 1-542-514-11 HEADPHONE (HP-M070) (ZV77/ZV77C) 1-542-516-11 HEADPHONE (HP-M061) (ZV71C) 1-542-517-11 HEADPHONE (HP-M046S) (ZV71) 1-542-529-11 HEADPHONE (HP-170) (ZV77D) 0 1-569-007-12 ADAPTOR, CONVERSION 2P (E33) 1-792-970-41 CORD, CAR BATTERY (DCC-E2455) (ZV71C,ZV77C) 3-252-375-01 TAPE,MAGIC (ZV71C,ZV77C) 3-252-434-11 MANUAL, INSTRUCTION (CAR KIT) (ZV71C,ZV77C) 3-253-769-11 MANUAL, INSTRUCTION(A) (ENGLISH,FRENCH) (ZV77:AEP,UK,E33,AUS/ZV77C/ZV77D:AEP) 3-253-769-21 MANUAL, INSTRUCTION(A) (GERMAN,ITALIAN) (ZV77:AEP/ZV77D:AEP) 3-253-769-31 MANUAL, INSTRUCTION(A) (SPANISH,PORTUGUESE) (ZV77:AEP,E33/ZV77C/ZV77D:AEP) 3-253-769-41 MANUAL, INSTRUCTION(A) (HUNGARIAN,POLISH) (ZV77:AEP/ZV77D:AEP) 3-253-769-51 MANUAL, INSTRUCTION(A) (CZECH,RUSSIAN) (ZV77:AEP/ZV77D:AEP) 3-253-771-11 MANUAL, INSTRUCTION(C) (ENGLISH,FRENCH) (ZV77:CND) 3-253-771-21 MANUAL, INSTRUCTION(C) (ENGLISH) (ZV71/ZV71C) 3-253-910-11 MANUAL, INSTRUCTION (TRADTIONAL CHINESE) (HK,TW) 3-253-910-21 MANUAL, INSTRUCTION (CHINESE) (ZV77:E18/ZV77D:E18,CH) 3-253-910-31 MANUAL, INSTRUCTION (KOREAN) (ZV77D:KR) The components identified by mark 0 or dotted line with mark 0 are critical for safety. Replace only with part number specified. Les composants identifiés par une marque 0 sont critiques pour la sécurité. Ne les remplacer que par une pièce portant le numéro spécifié. Ver 1.2 2003.08 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com XP-ZV71/ZV71C/ZV77/ZV77C/ZV77D REVISION HISTORY Clicking the version allows you to jump to the revised page. Also, clicking the version at the upper right on the revised page allows you to jump to the next revised page. Ver. Date Description of Revision 1.0 2003.04 New 1.1 2003.06 Addition of E33 / E33 / Hong Kong, Taiwan models (XP-ZV77 / ZV77C / ZV77D) 1.2 2003.08 Addition of Chinese model (XP-ZV77D) 1.3 2003.12 Change of Part No. for Ref. No. IC302 (RPC-03003) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com
