– 1 – Model Name Using Similar Mechanism CDX-3180 CD Drive Mechanism Type MG-363X-121 Optical Pick-up Name KSS-521A Model Name Using Similar Mechanism XR-2800 Tape Transport Mechanism Type MG-25E-136 SERVICE MANUAL AEP Model UK Model CHANGER CONTROL AUDIO MASTER MICROFILM CD player section Signal-to-noise ratio 96 dB Frequency response 10 - 20,000 Hz Wow and flutter Below measurable limit Cassette player section Tape track 4-track 2-channel stereo Wow and flutter 0.08 % (WRMS) Frequency response 30 - 18,000 Hz Signal-to-noise ratio Cassette type Dolby B NR Dolby NR off TYPE II, IV 67 dB 58 dB TYPE I 64 dB 55 dB Tuner section FM Tuning range 87.5 - 108.0 MHz Antenna terminal External antenna connector Intermediate frequency 10.7 MHz Usable sensitivity 9 dBf Selectivity 75 dB at 400 kHz Signal-to-noise ratio 65 dB (stereo), 68 dB (mono) Harmonic distortion at 1 kHz 0.7% (stereo), 0.4% (mono) Separation 35 dB at 1 kHz Frequency response 30 - 15,000 Hz SPECIFICATIONS – Continued on next page – CD Section TC Section MW/LW Tuning range MW : 531 - 1,602 kHz LW : 153 - 281 kHz Antenna terminal External antenna connector Intermediate frequency 10.71 MHz/450 kHz Sensitivity MW : 30 µV LW : 50 µV Power amplifier section Outputs Speaker outputs (sure seal connectors) Speaker impedance 4 - 8 ohms Maximum power output 35 W × 4 (at 4 ohms) Dolby noise reduction manufactured under license from Dolby Labo- ratories Licensing Corporation. “DOLBY” and the double-D symbol a are trademarks of Dolby Laboratories Licensing Corporation. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 2 – SERVICE NOTE CAUTION Use of controls or adjustments or performance of proce- dures other than those specified herein may result in haz- ardous radiation exposure. Notes on Chip Component Replacement • Never reuse a disconnected chip component. • Notice that the minus side of a tantalum capacitor may be dam- aged by heat. NOTES ON HANDLING THE OPTICAL PICK-UP BLOCK OR BASE UNIT The laser diode in the optical pick-up block may suffer electrostatic breakdown because of the potential difference generated by the charged electrostatic load, etc. on clothing and the human body. During repair, pay attention to electrostatic breakdown and also use the procedure in the printed matter which is included in the repair parts. The flexible board is easily damaged and should be handled with care. NOTES ON LASER DIODE EMISSION CHECK The laser beam on this model is concentrated so as to be focused on the disc reflective surface by the objective lens in the optical pick- up block. Therefore, when checking the laser diode emission, ob- serve from more than 30 cm away from the objective lens. NOTES ON PICK-UP FLEXIBLE BOARD The pick-up flexible board in this set is secured to the optical pick- up with an adhesive tape. Once the tape is removed, an adhering force becomes weak, and it cannot be reused. Therefore, if the optical pick-up is replaced, replace also the pick- up flexible board with a new one. SAFETY-RELATED COMPONENT WARNING!! COMPONENTS IDENTIFIED BY MARK ! OR DOTTED LINE WITH MARK ! ON THE SCHEMATIC DIAGRAMS AND IN THE PARTS LIST ARE CRITICAL TO SAFE OPERATION. REPLACE THESE COMPONENTS WITH SONY PARTS WHOSE PART NUMBERS APPEAR AS SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUBLISHED BY SONY. General Outputs Line outputs (2) Power antenna relay control lead Power amplifier control lead Telephone ATT control lead Tone controls Bass ± 10 dB at 100 Hz Treble ± 10 dB at 10 kHz Power requirements 12 V DC car battery (negative ground) Dimensions Approx. 178 × 100 × 173 mm (w/h/d) Mounting dimension Approx. 178 × 100 × 155 mm (w/h/d) Mass Approx. 2.2 kg Supplied accessories Parts for installation and connections (1 set) Decoy cover (1) Labels for optional rotary commander (2) Design and specifications are subject to change without notice. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 3 – TABLE OF CONTENTS 1. GENERAL Location of Controls............................................................... 4 Getting Started ........................................................................ 5 Setting the Clock .................................................................... 5 CD Player ............................................................................... 5 Cassette Player ....................................................................... 6 Radio ...................................................................................... 7 RDS ........................................................................................ 8 Other Functions .................................................................... 11 CD/MD Changer .................................................................. 12 Connections .......................................................................... 15 2. DISASSEMBLY 2-1. Front Panel Assy .............................................................. 17 2-2. Key Board ........................................................................ 17 2-3. CD Mechanism Block ...................................................... 18 2-4. Heat Sink .......................................................................... 18 2-5. CD Board ......................................................................... 19 2-6. Tape Mechanism Block .................................................... 19 2-7. Main Board ...................................................................... 20 2-8. Chassis (T) Sub Assy ....................................................... 20 2-9. Lever Assy........................................................................ 21 2-10. Servo Board...................................................................... 21 2-11. Roller Assy ....................................................................... 22 2-12. Chassis (OP) (O/S) Assy .................................................. 22 2-13. Optical Pick-up Block ...................................................... 23 3. ASSEMBLY OF MECHANISM DECK Housing ................................................................................ 24 Arm (Suction) ....................................................................... 24 Lever (LDG-A)/(LDG-B)..................................................... 25 Gear (Loading FT)................................................................ 25 Guide (C), Guide .................................................................. 26 Mounting Position of Main Motor Assy (M904) ................. 26 4. MECHANICAL ADJUSTMENTS .............................. 27 5. ELECTRICAL ADJUSTMENTS Tape Section ......................................................................... 27 Tuner Section........................................................................ 28 CD Section ........................................................................... 32 6. DIAGRAMS 6-1. Block Diagram –CD Section–.......................................... 33 6-2. Block Diagram –Tape Section– ....................................... 35 6-3. Block Diagram –Main Section– ....................................... 37 6-4. IC Pin Descriptions .......................................................... 39 6-5. Circuit Boards Location ................................................... 44 6-6. Printed Wiring Boards –CD Mechanism Section–........... 45 6-7. Schematic Diagram –CD Mechanism Section– ............... 47 6-8. Schematic Diagram –CD Section–................................... 50 6-9. Printed Wiring Board –CD Section– ................................ 53 6-10. Schematic Diagram –Control Section– ............................ 55 6-11. Printed Wiring Board –Control Section– ......................... 57 6-12. Printed Wiring Board –Main Section– ............................. 61 6-13. Schematic Diagram –Main Section–................................ 65 7. EXPLODED VIEWS 7-1. Cover Section ................................................................... 73 7-2. Front Panel Section .......................................................... 74 7-3. Chassis Section ................................................................ 75 7-4. CD Mechanism Section (1) .............................................. 76 7-5. CD Mechanism Section (2) .............................................. 77 7-6. CD Mechanism Section (3) .............................................. 78 7-7. Tape Mechanism Section ................................................. 79 8. ELECTRICAL PARTS LIST ................................... 80 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 4 – SECTION 1 GENERAL This section extracted from instruction manual. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 5 – www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 6 – www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 7 – www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 8 – www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 9 – www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 10 – www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 11 – www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 12 – www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 13 – www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 14 – www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 15 – www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 16 – www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 17 – SECTION 2 DISASSEMBLY Note : Follow the disassembly procedure in the numerical order given. 2-1. FRONT PANEL ASSY 2-2. KEY BOARD 1 PTT 2.6x14 3 PTT 2.6x6 5 PTT 2.6x6 4 PTT 2.6x6 9 claws 8 claws 0 front panel assy 6 PTT 2.6x10 7 cover 2 PTT 2.6x6 1 knob (VOL) 4 knob (D-BASS) 3 KEY board 2 P 2x8 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 18 – 2-3. CD MECHANISM BLOCK 2-4. HEAT SINK 5 PTT 2.6x6 1 PTT 2.6x10 2 PTT 2.6x6 3 CN401 6 bracket (CD) 4 CD mechanism block 1 PTT 2.6x10 4 heat sink 2 PTT 2.6x10 3 PTT 2.6x10 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 19 – 2-5. CD BOARD 2-6. TAPE MECHANISM BLOCK 1 CN802 3 CN403 2 CN404 5 PTT 2.6x10 4 ground point screw (PTT 2.6x6) 7 CD board 6 claw 4 CN321 2 PTT 2.6x6 3 PTT 2.6x6 5 tape mechanism block 1 CN301 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 20 – 2-7. MAIN BOARD 2-8. CHASSIS (T) SUB ASSY 2 MAIN board 3 insulating sheet 1 ground point screws (PTT 2.6x6) 4 chassis (T) sub assy 2 P 2x3 3 P 2x3 1 Unsolder the lead wires. red white black www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 21 – 2-9. LEVER ASSY 2-10. SERVO BOARD 4 claws 2 DISC IN SW board 7 lever (L) assy 3 tension spring (LR) 6 lever (R) assy 5 guide (disc) 1 PS 2x4 5 PS 2x4 1 CN3 3 P 2x3 4 loading motor assy 7 SERVO board 2 CN2 6 PS 2x4 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 22 – 2-12. CHASSIS (OP) (O/S) ASSY • When installing, take note of the positions arm (roller) and washers. (Fig. 1) 2-11. ROLLER ASSY Fig. 1 4 PS 2x3 5 LOAD SW board 1 tension spring (RA) 2 arm (roller) 3 roller assy washer arm arm washer washers 1 tension spring (angle) 8 compression spring (FL) 7 chassis (OP) (O/S) assy 9 compression spring (FL) 2 tension spring (KR1) 5 Fit lever (D) in the direction of the arrow. 3 damper (T) 4 damper (T) 6 Turn loading ring in the direction of the arrow. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 23 – 2-13. OPTICAL PICK-UP BLOCK 1 P 2x3 2 sled motor assy 3 optical pick-up block www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 24 – SECTION 3 ASSEMBLY OF MECHANISM DECK Note : Follow the assembly procedure in the numerical order given. HOUSING ARM (SUCTION) A part C part B part D part 8 Hold the hanger by bending the claw. 6 Fit projection on D part. 4 Fit claw on B part. 3 Put the housing under A part. 5 Fit projection on C part. 1 Install the catcher to the hanger. 2 Install the hanger onto two claws of the housing. 7 Holder the hanger by bending the claw. hanger housing 2 Move the arm (suction) in the arrow direction and fit on projection. 1 Fit the arm (suction) on the shaft. projection www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 25 – LEVER (LDG-A) / (LDG-B) GEAR (LOADING FT) shaft A shaft B 2 Fit the lever (LDG-B) on shafts A and B and install it. 3 type-E stop ring 2.0 shaft A shaft B shaft C 1 Fit the lever (LDG-A) on shafts A – C and install it. gear (LDG-D) 6 gear (loading FT) 7 polyethylene washer 1 tension spring (LD-2) 3 tension spring (LD-1) gear (LDG-FB) lever (LDG-A) hole hole 5 Align hole in the gear (LDG-D) with hole the lever (LDG-A). 4 Move the lever (LDG-B) in the arrow direction. 2 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 26 – GUIDE (C), GUIDE MOUNTING POSITION OF MAIN MOTOR ASSY (M904) 2 guide (C) 3 guide 1 three claws 2 precision screws +P 2x2 1 main motor assy (capstan/reel) 3 belt (25) 30˚ www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 27 – PRECAUTION 1. Wipe the following components with an absorbent cotton cloth moistened with alcohol before adjustment : PB head Pinch roller Idler Rubber belt Capstan 2. Demagnetize the PB head using a head demagnetizer. 3. Be careful not to use a magnetized screwdriver. 4. After the adjustment is completed, lock the adjustment parts using screws. 5. Unless otherwise specified, make adjustments at the specified voltage (14.4V). Torque Measurement Mode Torque Meter Meter Reading 35 – 65 g • cm FWD CQ-102C (0.49 – 0.90 oz • inch) FWD 0.5 – 5.0 g • cm Back Tension (0.01 – 0.07 oz • inch) 35 – 65 g • cm REV CQ-102RC (0.49 – 0.90 oz • inch) REV 0.5 – 5.0 g • cm Back Tension (0.01 – 0.07 oz • inch) 60 – 200 g • cm FF, REW CQ-201B (0.83 – 2.78 oz • inch) Tape Tension Measurement Mode Tension Meter Meter Reading FWD CQ-403A more than 60 g REV CQ-403R (more than 2.12 oz) SECTION 5 ELECTRICAL ADJUSTMENTS SECTION 4 MECHANICAL ADJUSTMENTS See the adjustment location from on page 31 for the adjustment. TAPE SECTION Tape Speed Adjustment Procedure : 1. Put the set into the FWD PB mode. Specification : Constant speed Speed checker Frequency counter – 1.5 to + 2.5 % 2,955 to 3,075 Hz Adjustment Location : See page 31. DOLBY Level Adjustment Setting : SHIFT button : ON (light up REP, SET UP and P MODE) Preset 9 (P MODE) button : ON (light up P MODE and n) Preset 10 (n) button : NR off Procedure : 1. Put the set into the FWD PB mode. 2. Adjust RV101 (L-CH) and RV201 (R-CH) on main board so that level meter reading is – 6 ± 0.5 dB (0.37 to 0.41 V). Adjustment Location : See page 31. 0 dB = 0.775 V LINE OUT REAR set 10 k Ω speed checker or frequency counter test tape WS-48A (3 kHz, 0 dB) main board TP (DOLBY) L-CH R-CH test tape P-4-D400 (400 Hz, 0 dB) level meter set www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 28 – TUNER SECTION Cautions during repair When the tuner unit is defective, replace it by a new one because its internal block is difficult to repair. Procedure : 1. Set to the test mode. 2. Push the TUNER button and set to FM. Display FM Auto Scan/Stop Level Adjustment Setting : D-BASS switch : OFF TUNER button : FM 3. Push the preset 3 button. Display 4. Adjust with the volume RV2 on TU1 so that the “FM” indica- tion turns to “ ” indication on the display window. But, in case of already indicated “ ”, turn the RV2 so that put out light “ ” indication and adjustment. Display 0 dB = 1 µV TEST MODE This set have the test mode function. In the test mode, FM Auto Scan/Stop Level and MW Auto Scan/Stop Level adjustments can be performed easier than it in ordinary procedure. 1. Set the “POWER SELECT” switch (S501) is “OFF” position. 2. Turn ON the regulated power supply. (All LEDs on the set lights up, and the clock is displayed.) 3. Push the preset 4 button. 4. Push the preset 5 button. 5. Press the preset 1 button for more than two seconds. 6. Then the display indicates all lights, the test mode is set. 1. Push the OFF button. Note on Adjustment The adjustments of tuner section, should be performed according to the following sequence. 1. FM Auto Scan/Stop Level Adjustment 2. FM Stereo Separation Adjustment 3. FM RDS S-Meter Adjustment 4. MW Auto Scan/Stop Level Adjustment Carrier frequency : 98.00 MHz Output level : 22 dB (12.6 µV) Mode : mono Modulation : 1 kHz, 22.5 kHz deviation (30%) antenna terminal FM RF signal generator 0.01 µF set REG SHUF REG SHUF REG SHUF Adjustment Location : See page 31. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 29 – Procedure : 1. Set to the test mode. (See page 28.) 2. Push the TUNER button and set to FM. Display 3. Push the preset 3 button. Display 4. Push the preset 10 button. 5. Adjust RV31 so that the display indication is “16.0”. Display FM RDS S-Meter Adjustment Setting : D-BASS switch : OFF TUNER button : FM FM Stereo Separation Adjustment Setting : D-BASS switch : OFF TUNER button : FM Carrier frequency : 98.00 MHz Output level : 70 dB (3.2 mV) Mode : stereo Modulation : main :1 kHz, 20 kHz deviation (26.5%) sub :1 kHz, 20 kHz deviation (26.5%) 19 kHz pilot : 7.5 kHz deviation (10%) L-CH stereo separation : A – B R-CH stereo separation : C – D The separations of both channels should be equal. Specification : Separation more than 30 dB Adjustment Location : See page 31. FM stereo Level meter Level meter signal generator connection reading (dB) output channel L-CH L-CH A B R-CH L-CH Adjust RV4 on TU1 for maximum reading. R-CH R-CH C D L-CH R-CH Adjust RV4 on TU1 for maximum reading. Procedure : antenna terminal LINE OUT REAR 0.01 µF 10 k Ω set level meter FM RF signal generator antenna terminal FM RF signal generator 0.01 µF set Carrier frequency : 98.00 MHz Output level : 35 dB (56.2 µV) Mode : mono Modulation : no modulation REG SHUF REG SHUF REG SHUF Specification : Display indication : 15.8 to 16.2. Adjustment Location : See page 31. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 30 – Carrier frequency : 999 kHz 30% amplitude modulation by 1 kHz signal output level : 33 dB (44.7 µV) Procedure : 1. Set to the test mode. (See page 28.) 2. Push twice the TUNER button and set to MW. Display 3. Push the preset 3 button. Display 4. Adjust with the volume RV1 on TU1 so that the “MW” indica- tion turns to “ MW” indication on the display window. But, in case of already indicated “ MW”, turn the RV1 so that put out light “ ” indication and adjustment. Display MW Auto Scan/Stop Level Adjustment Note : This adjustment should be performed after the FM Auto Scan / Stop Level Adjustment is done. Setting : D-BASS switch : OFF TUNER button (twice) : MW Adjustment Location : See page 31. antenna terminal set AM RF signal generator AM dummy antenna (50 Ω) 65 pF 15 pF set 30 Ω REG SHUF TP REG SHUF TP REG SHUF TPwww. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 31 – – 32 – Adjustment Location : – set upper view – – set lower view – TAPE SPEED ADJ TU1 RV1 MW AUTO SCAN/STOP LEVEL ADJ RV2 FM AUTO SCAN/STOP LEVEL ADJ RV4 FM STEREO SEPARATION ADJ RV31 FM RDS S-METER ADJ RV201 (R-CH) RV101 (L-CH) DOLBY LEVEL ADJ R-CH L-CH TP (DOLBY) DOLBY LEVEL ADJ CD SECTION Note : 1. CD Block basically constructed to operate without adjustment. Therefore, check each item in order given. 2. Use YEDS-18 disc (3-702-101-01) unless otherwise indicated. 3. Use the oscilloscope with more than 10 MΩ impedance. 4. Clean an objective lens by an applicator with neutral detergent when the signal level is low than specified value with the following checks. Focus Bias Adjustment Setting : This adjustment is performed with the set placed horizontally. Focus Gain Adjustment (Coarse adjustment) This adjustment is not required unless the following parts are replaced: • Optical pick-up • RV4 Procedure : 1. Set RV4 to the standard position. (mechanical center) 2. Check whether operation noise (while noise type) caused by the 2-axis device (lens section of the optical pick-up) is abnormally loud. If the operation noise is too loud, turn RV4 slightly counter- clockwise. • If the gain is too low : Focus does not function and no music is selected. • If the gain is too high : Noise caused by scratches and dust is heard and the operation becomes unstable. Adjustment Location : servo board Adjustment Location : servo board (component side) Procedure : 1. Connect an oscilloscope between TP (RF) and TP (RF GND) on the servo board. 2. Connect the power supply. 3. Push the RESET button (SW701) on the key board. 4. Insert the disc (YEDS-18) and playback. 5. Adjust RV1 so that the oscilloscope waveform is clear and check RF signal level is correct or not. Note : Clear RF signal waveform means that the sharp “≈ ” can be clearly distinguished at the center of the waveform. • When observing the eye pattern, set the oscilloscope to AC range and raise the vertical sensitivity so that it may be easily seen. Adjustment Location : servo board oscilloscope servo board TP (RF) TP (RF GND) VOLT/DIV : 200 mV TIME/DIV : 500nS level : 1.0 – 1.5 Vp-p RF signal waveform FOCUS GAIN ADJ RV4 RV1 FOCUS BIAS ADJ IC3 CN2 CN1 IC1 TP (RF) CN3 IC2 TP (RF GND) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 6-1. BLOCK DIAGRAM — CD SECTION — WX-C570R – 33 – – 34 – 14 RF 59 CLKO 57 XLTO 56 DATO 21 PCMD 20 LRCK 22 BCK 34 XTAI 50 XRST DIGITAL SIGNAL PROCESSOR IC1 D/A CONVERTER IC801 55 CNIN 54 SEIN 1 FOK 3 MDP 46 47 SQSO GFS SCOR 49 SQCK 51 SENS 52 DATA 53 XLAT CLOK 5 OPTICAL PICK-UP KSS-521A SERVO 5V PD LD RV1 FOCUS BIAS RV4 FOCUS GAIN LD DRIVE Q1,2 35 PD1 36 PD2 39 E 38 F 31 RFO 19 CLK 20 XLT 21 DATA RF AMP, SERVO CONTROL IC2 37 FE BIAS 1 FEO 2 FEI 16 SLO 22 XRST 23 C. OUT 24 SENS 25 FOK 6 FEO 13 TAO 34 PD 33 LD TRACKING FOCUS M902 (SLED) M901 (SPINDLE) M903 (LOADING) 16 CH2+ 15 CH2– 18 CH1+ 17 CH1– 19 CH1 IN 22 CH2 IN 24 CH3 IN 3 CH4 IN FOCUS/TRACKING COIL DRIVE, MOTOR DRIVE IC3 13 CH3+ 14 CH3– 12 CH4+ 11 COM 6 FWD 7 REW 4 CTL1 04 10 CH5+ M M M I - V AMP X401 16.9344MHz D IN 4 LRC IN 6 BCK IN CLKO 3 DI 12 VOUTL 9 VOUTR 19 9 DOUT 1 LRCK 2 BCKI 4 CLK 11 LRCO 10 BCKO 14 MOD1 15 MOD2 16 DB/DS 17 DM1 18 MUTE CD 1 XTI 54 49 20 53 XTO LD ON LM LOD LMEJ 48 62 FOK 29 CD RST 56 CNIN CTL1 R-CH 41 SQ SI 42 SQ CKO 64 SENS 44 SO SW2 (SELF) 28 EMPHON 27 CD MUT 38 DBCNT1 37 DBCNT2 CD SYSTEM CONTROL IC401(1/2) DSP IC802 40 61 GFS SCOR SELFSW D-SW 63 22 CDON 21 CDMON 8V REG Q464,465 5V REG Q462,463 45 LAT 46 CKO SW1 (DISC IN) IN SW 51 MAIN SECTION 1 : CD 27 43 BATT MD8V SERVO 5V Q401 36 DBCNT3 SW4 (DOWN) 50 SW3 (LIMIT) 52 LSW Q461 Signal Path CD L-CH SECTION 6 DIAGRAMS w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 6-2. BLOCK DIAGRAM — TAPE SECTION — WX-C570R – 35 – – 36 – SW701 (RESET) Q951 FL DRIVE IC701 SYSTEM CONTROL IC501(2/2) X402 5MHz 111 113 114 109 110 112 19 18 16 17 14 20 105 106 107 108 5 2 4 4 6 104 7 76 35 46 47 78 49 18 21 20 22 77 17 90 55 36 37 F ROUT TAPE MUTE AMS IN AMS ON POS0 POS1 POS2 POS3 BUS ON BUS SO BUS SI BUS CKI/O BU IN SYSRST RESET RAM BU RE IN0 RE IN1 CD SYSTEM CONTROL IC401(2/2) 19 17 67 16 18 66 60 LINK OFF UNI SO BUS ON UNISI UNICKI BUIN RST X2 X1 FL CE FL BLK FL SO FL CKO LM EJ LM LOD CM ON REEL TAPE ON AD ON KEY IN0 KEY IN1 RC IN1 RC IN0 40 ILL ON 98 97 100 99 28 29 26 27 FL CE FL BLK FL DATA FL CL LED DRIVE IC702 LED LCK LED OE LED CLK LED DATA 4 17 3 2 60 6 11 59 14 13 LCK OE Q0 Q6 CLK DATA BATT CHECK 1 12 6 4 3 2 9 8 11 10 13 HIGH VOLT CHECK Q952 D-BASS SWITCH SW700 8 3 2 1 6 5 4 7 BATT BATT OUT VDD BU 5V BU5V 69 70 CAPSTAN/REEL MOTOR DRIVE Q324,325 48 KEY IN2 SW702 ROTARY ENCODER 3V REG Q481 POWER SWITCH Q482,483 LED SWITCH Q702–705 10V REG Q473,474 POWER SWITCH Q471,472 FL701 AUTO MUSIC SENSOR DOLBY NR FWD R-CH HP901 PLAYBACK HEAD TAPE L-CH REV R-CH 7 9 (TAPE OPERATION) EJECT FF(NOR) REW(NOR) REV FWD (TAPE DET) M M LOADING MOTOR DRIVE IC321 LOADING/TAPE OPERATION MOTOR M904 CAPSTAN/REEL MOTOR Q491 BATT BATT FLMT+B 5V REG Q701 DRIVER+B PLAT+B LED+B LCD+B PON MAIN SECTION KEY-ACK DETECT Q561 KEY-ACK DETECT Q562 BU5V BU5V R-CH 24 34 32 NR ON EQ MTL/NORMAL MUTE AMS AMS/PLAY BUFFER REEL SENSOR 8.5V REG Q321–323 BATT TA8.5V KEY ACK I/F+B J501 29 27 FL RL L R L R TAPE EQ/DOLBY NR IC301 RV101 MAIN SECTION 3 2 FWD/REV L OUT MTL ON DOL ON DOLBY LEVEL (L-CH) CN951 BUS INTERFACE IC951 RAM RESET IC562 RESET IC561 LCD+B LCD+B LED+B FLMT+B D568 04 D565 D361 D562 D561 D732–735 LED+B D736–742 D713–716, 730,731, LSW702,718 LSW701,703–712, 717,719–723 : TAPE Signal Path (REMOTE IN) LSW701–723 (BUS CONTROL IN) 1 1 2 2 Q8 Q11 13 16 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com WX-C570R 6-3. BLOCK DIAGRAM — MAIN SECTION — – 37 – – 38 – LPF Q41 D1 FM 8V TU 8V AM 8V AM 8V L-CH OUT R-CH OUT AMDET S-METER SD ST IFC AM IFC FM VCO VT LO/DX SEEK TUNER UNIT TU1 18 16 11 10 12 19 53 62 57 13 20 22 11 21 6 5 4 13 35 37 38 33 16 CL 18 DI 17 CE TONE/ DBB 36 34 OFF ON S501 POWER SELECT ELECTRONIC VOLUME IC302 POWER AMP IC306 CN900 CN304 R-CH R –2 –1 X51 7.2MHz X501 32.768KHz X502 3.68MHz SI FM ST SD IN VSM TU MUTE SO PLL CKO CE X1A X0A X0 X1 AF SEEK 04 FL RL 1 3 5 FL+ FL– 1 9 21 20 L 10 MUTE1 2 STBY 11 7 9 RL+ RL– 10 2 4 12 3 11 13 14 7 15 5 6 BUZZER DRIVE Q591 START MUTE Q921,922 5V REG Q71 +B SWITCH Q81 MUTE CONTROL Q903 R-CH Q151 Q351 Q31 S-METER RV31 R-CH TAPE SECTION CD SECTION TAPE L-CH CD L-CH 16 18 9 64 15 FM DET 16 23 MPX 20 LVIN AM IF AM OSC FM OSC PD LO/DX SEEK OUT X1 X0 DO DI CLK CE 1 20 74 93 83 6 5 4 2 PLL IC51 FM/AM SELECT IC303 9 10 11 19 73 X81 4.332MHz OSCO OSCI 5 4 92 VOL CKO VOL CE VOL SO MUTE 67 68 66 84 15 85 117 116 118 2 3 4 7 6 8 9 10 11 31 101 102 81 100 BEEP AMP ON TU ON FM ON P ON POR SEL TEL MUTE ILL IN ACC IN TEST SYSTEM CONTROL IC501(1/2) TEL MUTE CONTROL Q902 6V REG IC941 19 ACC CHECK Q971 DIMMER CONTROL Q901 BATT HIGH VOLT CHECK Q923 BATT MODE 2 MODE 1 STBY AM 8V AM 8V +6V PUL 5V FM 8V FM 8V Q1001 VCC AMP +B ANT +B COM 8V BATT RDS 5V TU 5V TU 8V COM 8V R-CH FR+ FR– RR+ RR– AMP REM ANT REM ATT ILL ACC TEST POWER SUPPLY IC901 BZ591 (BUZZER) ANT FM ANT AM +B FM +B TU +B AM 1 2 8 9 10 BU 5V D922 2 1 TAPE SECTION 3 J1 (ANTENNA) BATT D564 D569 BATT PON Signal Path : FM : MW : TAPE : CD BUS AUDIO IN MUTE DRIVE Q451 CN803 R-CH R-CH Q801 Q802 9 6 65 12 8 MUTE DRIVE Q924 MUTE DRIVE Q352 Q181 Q182 L -1 -2 -3 -4 R L R LINE OUT FRONT LINE OUT REAR AM 8V 1 2 Q61 SWITCH IC41 6 3 7 5 Q82 MPTH DAVN RDS SDA SCL MPTH DAVN SDA SCL 2 8 9 10 RDS MODULATOR IC81 52 72 70 71 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 39 – 6-4. IC PIN DESCRIPTIONS • IC401 µPD78054GC-484-3B9 (CD SYSTEM CONTROL) Pin No. Pin Name I/O Pin Description 1 – 3 NCO I Not used. 4 AVSS — GND for A/D conversion. 5, 6 NCO O Not used. 7 AVREF — Reference voltage power supply for D/A conversion. (+5 V) 8 – 15 NCO O Not used. 16 UNISI I Serial data input (for SONY BUS) 17 UNISO O Serial data output (for SONY BUS) 18 UNICKI I Serial clock input (for SONY BUS) 19 LINKOFF O Link off output 20 NCO O Not used. 21 CDMON O CD mechanism power control output 22 CD-ON O CD power control output 23 – 26 NCO O Not used. 27 CDMUT O CD mute control output 28 EMPHON O Emphasis control output 29 CDRST O CD signal process IC reset output 30 – 32 NCO I Not used. 33 VSS — Microcomputer GND 34 TBTGSEL I CD traverse/tracking gain automatic adjustment select input 35 NCO I Not used. 36 – 38 DBCNT3 – 1 O D-BASS (Digital Bass Boost) IC control output 3 – 1 39 DB RST O D-BASS (Digital Bass Boost) IC reset output 40 GFS I GFS signal detection input 41 SQ SI I SUB Q data input 42 SQ CKO O SUB Q clock output 43 NCO I Not used. 44 CD SO O CD signal process serial data output 45 CD LAT O CD signal process latch output 46 CD CKO O CD signal process serial clock output 47 NCO I Not used. 48 F OK I Focus signal detection input 49 LDON O Laser ON/OFF control output 50 DSW I DOWN switch detection input 51 IN SW I Disc insert detection input 52 LSW I Sled limit switch detection input 53 LMLOD O Loading motor control output (Loading direction) 54 LMEJ O Loading motor control output (Eject direction) 55 NCO I Not used. 56 CTL1 O Driver IC control output 1 57 – 59 NCO O Not used. 60 RST — Reset input 61 SCOR I SCOR signal detection input 62 CNIN I Track jump number count input 63 SELFSW I Disc self store detection input 64 SENS I SENS signal detection input 65 NCO O Not used. 66 BUIN I Backup power detection input 67 BUSON I BUS ON control input 68 VDD — Microcomputer power supply 69 X2 — Main oscillator output (5 MHz) 70 X1 — Main oscillator input (5 MHz) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 40 – Pin No. Pin Name I/O Pin Description 71 GND — GND 72 (OPEN) — Not used. 73 GND — GND 74 AVDD — Power supply for A/D conversion. 75 AVREF — Reference voltage power supply for A/D conversion. 76, 77 NCO I Not used. 78 NIL I Not used. (Pull up 5 V.) 79, 80 NCO I Not used. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 41 – • IC501 MB90574PFV-G-118-BND (SYSTEM CONTROL) Pin No. Pin Name I/O Pin Description 1 — — Not used. 2 BUS CKO — Not used. 3 — — Not used. 4 LM-LOD O Tape loading motor control output (Loading direction) 5 LM-EJ O Tape loading motor control output (Eject direction) 6 CM-ON O Tape capstan motor control output 7 TAPE ON O Tape power control output 8 VCC — Power supply pin (+5 V) 9 PLL SI I PLL data input 10 PLL SO O PLL data output 11 PLL CKO O PLL clock output 12 FLA DI — Not used. 13 LED DATA O LED driver control serial data output 14 LED CLK O LED driver control serial clock output 15 BEEP O BEEP output 16 — — Not used. 17 SYSRST O System reset output 18 BUS ON O Bus ON control output 19 PLL CE O PLL chip enable output 20 BUS SI O Serial data input (for SONY BUS) 21 BUS SO O Serial data output (for SONY BUS) 22 BUS CKI/O I/O Serial clock input/output (for SONY BUS) 23 FLASH W I Flash write in mode detection input 24 SIRCS I Remote commander input (Not used in this set.) 25 — — Not used. 26 FL SO O FL serial data output 27 FL CKO O FL serial clock output 28 FL CE O FL serial chip enable output 29 FL BLK O FL blank control output 30 – 32 — — Not used. 33 VSS — GND 34 C — Power stabilization capacitor pin 35 AD ON O Power control output of A/D conversion. 36, 37 RE IN0, 1 I Rotary encoder input 0, 1 38 DVCC — D/A converter VREF input 39 DVSS — GND of D/A converter. 40 ILL ON O Illumination power control output 41 TAPE ING — Not used. 42 AVCC — Analog power supply pin (+5 V) 43 AVRH — A/D converter VREF+ input 44 AVRL — A/D converter VREF- input 45 AVSS — Analog GND 46, 47 KEY IN0, 1 I Key input 0, 1 48 KEY IN2 I D-BASS switch input 49 RC IN0 I Rotary commander input 0 50 DSTSEL0 I Destination select input 0 (Fixed at “L” in this set.) 51 DSTSEL1 I Destination select input 1 (Fixed at “L” in this set.) 52 RDS MTPH I Tuner multi-pass input 53 VSM I S-Meter voltage detection input 54 VCC — Power supply pin (+5 V) 55 RAM BU I RAM reset detection input 56 POW SEL I Power select initial setting input www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 42 – Pin No. Pin Name I/O Pin Description 57 SD IN I Signal detector input 58 WIDE O WIDE/NARROW select output (Not used in this set.) 59 LED OE O LED driver control over write output 60 LED LCK O LED driver control serial latch output 61 AM ST I AM stereo input (Not used in this set.) 62 FM ST I/O Used in conjunction with stereo input/monaural output (FM mode) 63 VSS — GND 64 SEEK OUT O SEEK OUT output 65 TU MUTE O Tuner mute output 66 VOL SO O Electric volume serial data output 67 VOL CKO O Electric volume serial clock output 68 VOL CE O Electric volume serial chip enable output 69 — — Not used. 70 RDS SDA I RDS serial clock input 71 RDS SCL I RDS serial data input 72 RDS DAVN I RDS IC data taking in detection input 73 X1A — Low speed oscillation input (32.768 kHz) 74 X0A — Low speed oscillation input (32.768 kHz) 75 — — Not used. 76 KEY ACK I Key input acknowledge 77 BU IN I Back-up power detection input 78 RC IN1 I Rotary commander input 79, 80 — — Not used. 81 ACC IN I Accessory power detection input 82 — — Not used. 83 AF SEEK O AF SEEK output 84 MUTE O System mute control output 85 AMP ON O Power amplifier power control output 86 HSTX — Connect to power supply pin. 87 MD2 — Connect to GND. 88, 89 MD0, 1 — Connect to power supply pin. 90 RESET I Microcomputer reset input 91 VSS — GND 92 X0 — High speed oscillation input (3.68 MHz) 93 X1 — High speed oscillation input (3.68 MHz) 94 VCC — Power supply pin (+5 V) 95 – 99 — — Not used. 100 TEST I Test mode setting detection input 101 TEL MUTE I Telephone mute detection input 102 ILL IN I Illumination line detection input 103 — — Not used. 104 REEL I Tape reel table rotation detection input 105 POS0 I Tape position detection input 0 106 POS1 I Tape position detection input 1 107 POS2 I Tape position detection input 2 108 POS3 I Tape position detection input 3 109 TAPE MUTE O Tape mute output 110 AM IN I AM stereo detection input 111 F ROUT O Tape forward/reverse detection output 112 AMS ON O Tape AMS control output 113 MTL ON I Auto METAL detection input 114 DOL ON O Tape DOLBY control output www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 43 – Pin No. Pin Name I/O Pin Description 115 DOL B/C O Tape DOLBY B/C select control output (Not used in this set.) 116 FM ON O FM ON output 117 TU ON O Tuner ON output 118 P-ON O System power control output 119 VSS — GND 120 — — Not used. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 44 – 6-5. CIRCUIT BOARDS LOCATION DISC IN SW board LOAD SW board KEY board REEL SENSOR board MAIN board CD board SUB board SERVO board LIMIT SW board SENSOR board tuner unit (TUX-006/2 (E)) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 69 – • IC Block Diagrams IC1 CXD2507AQ (SERVO BOARD) IC801 PCM1717E-ST2 IC3 BA6796FP-T1 IC802 SM5852FS-E2 XLON SPOD SPOC SPOB SPOA CLKO VDD CNIN SEIN CLOK XLAT XLTO DATO 52 53 54 55 56 57 58 59 60 61 62 63 64 51 SERVO AUTO SEQUENCER 33 34 35 36 37 38 39 40 41 42 43 45 46 47 48 49 50 44 DATA XRST SENS MUTE SQCK SQSO EXCK SBSO SCOR VSS WFCK EMPH DOUT C4M FSTT XTSL XTAO XTAI MNTO 20 21 22 23 24 25 26 27 29 30 31 32 28 LRCK PCMD BCLK GTOP XUGF XPCK VDD GFS RFCK C2PO XROF MNT3 MNT1 1 2 3 4 5 6 7 8 9 10 11 12 16 17 18 19 13 14 15 FOK MON MDP MDS LOCK TEST FILO FILI PCO VSS AVSS CLTV AVDD RF BIAS ASYI ASYO ASYE WDCK 5 14 CPU INTERFACE SUB CODE PROCESSOR DIGITAL CLV EFM DEMODULATOR DIGITAL PLL ASYMMETRY CORRECTOR 5 D/A INTERFACE ERROR CORRECTOR 3 6 3 16K RAM DIGITAL OUT CLOCK GENERATOR 4 3 4 5 6 7 18 19 20 17 16 15 14 8 9 10 13 12 11 2 1 CLK CONTROL INPUT INTERFACE DIGITAL FILTER 5LEVE DAC LOWPASS FILTER CMOS AMP 5LEVEL DAC LOWPASS FILTER CMOS AMP MODE CONT ROL XTI DGND VDD LRCIN DIN BCKIN ZERO D/C R VOUTR AGND VCC VOUTL D/C L MODE RSTB MD/DM0 MC/DM1 ML/MUTE CLKO XTO NOISE SHAPER 1 2 3 4 5 6 7 8 9 10 16 15 14 13 12 11 DIGITAL SIGNAL PROCESSOR OUTPUT INTERFACE SYSTEM CLOCK INPUT INTERFACE SEQUENTIAL CONTROL MUTE CONTROL MODE CONTROL LRCI BCKI DI CLK VSS RSTN TESTN MUTEN DB/DS MOD2 MOD1 OPT VDD LRCO BCKO DOUT 1 2 3 4 5 6 7 8 9 10 11 12 13 14 OPOUT CH4-IN CH4 CTL1 CTL2 FWD REV TRAY GND CH3 – CH5 – COM CH4 + CH3 + CH3-IN CH3 VREF CH2 CH2-IN VCC VCC CH1 – CH2 – CH1-IN OP IN – CH1 CH1 + OP IN + CH2 + DRIVE BUFFER DRIVE BUFFER DRIVE BUFFER DRIVE BUFFER DRIVE BUFFER DRIVE BUFFER DRIVE BUFFER DRIVE BUFFER DRIVE BUFFER LEVEL SHIFT LEVEL SHIFT LEVEL SHIFT LEVEL SHIFT THERMAL SHUT DOWN 15 16 17 18 19 20 21 22 23 24 25 26 27 28 LOGIC CTL1 CTL2 FWD REV V/I www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 70 – IC2 CXA1782BQ (SERVO BOARD) 36 35 34 33 32 31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 37 38 39 40 41 42 43 44 45 46 47 48 PHD 2 PHD 1 PHD LD RF O RF I CP CB CC1 CC2 FOK SENS C.OUT XRST DATA XLT CLK VCC ISET SL O SL M SL P TA O TA M FSET TG2 TGU SRCH FE O FLB FGD FDFCT FE M FEI FEO FE BIAS F E EI VEE TED LPFI TEI ATSC TZC TDFCT VC APC LEVEL S FOK MIRR RF IV AMP1 RF IV AMP2 FE AMP TTL IIL FZC COMP DFCT IIL TTL IIL DATA REGISTER INPUT SHIFT REGISTER ADDRESS DECODER OUTPUT DECODER TTL IIL TOG1-3 BAL1-3 FS1-4 TG1-2 TM1-7 PS1-4 F IV AMP E IV AMP BAL1 BAL2 BAL 3 TE AMP TZC COMP DFCT TM1 DFCT FS4 ATSC WINDOW COMP TOG1 TOG2 TOG3 FCS PHASE COMPENSATION FS1 F SET TG2 TM7 TM3 TM4 TM5 TM6 ISET TRACKING PHASE COMPENSATION HPF COMP LPF COMP TG1 FS2 TM2 RF M www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 71 – IC702 BU2092F-T1 IC51 BU2624FV-E2 IC81 SAA6588T-118 IC901 BA3918-V2 IC561 RN5VD33AA-TL IC306 HA13158 1 2 3 4 5 6 7 8 9 10 16 15 14 13 12 11 CONTROL CIRCUIT 12 BIT SHIFT REGISTER 12 BIT STORAGE REGISTER OUTPUT BUFFER (OPEN DRAIN) 17 18 VDD OE Q11 Q10 Q9 Q8 Q7 Q6 Q5 Q4 Q3 Q2 Q1 Q0 LCK CLOCK DATA VSS PHASE DET PRESCALER MAIN COUNT IF COUNT CTL 20BIT COUNT SHIFT REGISTER LATCH REFERENCE DIVIDER I/O CTL 1 2 4 5 6 7 9 10 20 18 17 16 15 14 13 12 11 19 XIN CE CK DA CD P0 P1 P3 XOUT VSS PD VDD FMIN AMIN P2 IFIN SD P4 SCOUT MRO MPTH TCON OSCO OSCI VSSD VDDD DAVN SDA VREF MPX VSSA VDDA AFIN MAD PSWN SCL 2 1 6 15 11 13 16 14 12 INTERFACE REGISTER SIGNAL QUALITY DECODER CLOCKED COMPARATOR POWER SUPPLY & RESET TEST CONTROL OSCILLATOR & CLOCK PAUSE DETECTOR MULTI PATH DETECTOR 57kHz 8th ORDER BAND-PASS FILTER RDS/RDBS DECODER RDS/RDBS DEMODULATOR IIC BUS SLAVE TRANSCEIVER 17 18 CIN 19 LVIN 20 8 7 DATA CLOCK DATA CLOCK 4 4 5 9 10 3 4 5 + – + – + – + – OVER VOLTAGE PROTECT REGULATOR 1 2 3 4 5 6 7 8 9 10 12 11 NC MODE2 MODE1 STB VDD AMP VCC ANT COM AM FM GND 1 2 3 4 5 CD NC OUT VDD GND RESET 1 INPUT BUFFER 1 INPUT BUFFER 2 INPUT BUFFER 3 INPUT BUFFER 4 AMP1 _ + AMP2 _ + 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 AMP3 _ + AMP4 _ + F.L STBY FL+ GND1 FL– VCC RL+ GND3 RL– MUTE1 R.L GND2 R.R VCC2 RR+ GND4 RR– VCC3 FR+ GND5 FR– RIPPLE F.R www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 72 – IC302 LC75374E IC951 BA8270F-E2 IC301 CXA2510AQ-T4 IC321 LB1638MTP-T1 + – + – + – + – + – 1 2 3 4 5 6 7 8 9 10 20 19 18 17 16 15 14 13 12 11 21 22 23 26 27 28 29 30 31 32 33 34 37 38 39 40 24 25 PBFB2 PBRIN2 PBREF2 PBFIN2 35 36 PBGND VCT PBFIN1 PBREF1 PBRIN1 PBFB1 PBEQ2 PBOUT2 VCC TAPEIN2 AUXIN2 MSLPF LINEOUT2 TCH2 NC PLAY FF MSTC DGND MSOUT NC NRSW INSW TAPESW MSMODE DRSW MSSW NC TCH1 LINEOUT1 DIREF AUXIN1 TAPEIN1 PBEQ1 PBOUT1 GND F2 120µ/ 70µ X1 X1 VCT + F1 120µ/ 70µ NR OFF/B F3 LPF VCC DETECT MS ON/ OFF NR MODE FWD/RVS TAPE EQ TAPE/AUX NR BIAS NR MS MODE OFF/B T2 T1 + – + – + – + – + – + – + – + – + – + – + – + – + – + – DECODER LATCH SHIFT REGISTER CONTROL – + + – 1 2 3 4 5 6 7 8 9 10 20 19 18 17 16 15 14 13 12 11 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 LSELO L4 L3 L2 L1 VDD R1 R2 R3 R4 RSELO RVRIN RCOM RT1 RT2 RT3 RTOUT RSIN NC NC RSB1 RSB2 RFIN RFOUT RROUT VSS CL DI CE VREF LROUT LFOUT LFIN LSB2 LSB1 NC NC LSIN LTOUT LT3 LT2 LT1 LCOM LVRIN 1 2 3 4 5 6 7 8 9 10 14 13 12 11 BUS ON SWITCH RESET SWITCH BATTERY SWITCH BUS ON RST BATT CLK VREF DATA GND VCC RST BUS ON CLK IN BU IN DATA IN DATA OUT 1 2 3 4 5 6 7 8 9 10 GND IN1 VCC IN2 GND N.C. OUT2 VS OUT1 N.C. CONTROL LOGIC www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 73 – SECTION 7 EXPLODED VIEWS N N NOTE: • The mechanical parts with no reference number in the exploded views are not supplied. • Items marked “*” are not stocked since they are seldom required for routine service. Some delay should be anticipated when ordering these items. • -XX and -X mean standardized parts, so they may have some difference from the original one. • Color Indication of Appearance Parts Example : KNOB, BALANCE (WHITE) ... (RED) Parts Color Cabinet’s Color • Accessories and packing materials and hardware (# mark) list are given in the last of this parts list. The components identified by mark ! or dotted line with mark. ! are critical for safety. Replace only with part number specified. 7-1. COVER SECTION Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 1 4 4 4 4 #4 #2 #2 #2 #2 #2 #2 #2 2 3 * 1 3-012-507-01 COVER 2 1-776-527-71 CORD (WITH CONNECTOR) (ISO) (POWER) * 3 3-012-508-22 HEAT SINK 4 3-919-171-01 SCREW (2.6X6) (C TIGHT) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 74 – 7-2. FRONT PANEL SECTION Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark FL701 #3 #3 59 63 60 61 62 65 64 67 68 69 70 71 57 52 51 53 54 55 56 58 72 66 51 3-021-889-01 PLATE, TRANSPARENT 52 3-021-893-01 SHEET, INDICATION 53 3-736-833-11 EMBLEM (NO.3), SONY 54 3-012-487-11 BUTTON (TUNE) 55 3-012-486-11 BUTTON (TAPE) 56 3-012-485-11 BUTTON (CD) 57 3-013-018-01 KNOB (VOL) 58 3-021-891-01 BUTTON (DSPL) * 59 A-3313-770-A KEY BOARD, COMPLETE 60 3-015-164-01 SHEET (FL), INSULATING 61 3-014-207-01 SPRING (CASSETTE LID) 62 3-012-483-01 DOOR, CASSETTE 63 3-012-505-01 KNOB (D-BASS) 64 3-012-484-01 BUTTON (CD EJECT) 65 3-012-488-01 BUTTON (10 KEY) 66 3-012-503-01 PLATE, LIGHT INTERCEPTION 67 3-021-890-01 BUTTON (PTY) 68 3-012-521-11 BUTTON (OFF) 69 X-3374-759-1 FRONT ASSY 70 3-012-490-11 BUTTON (AMS) 71 2-127-723-01 SPRING (KNOB) 72 3-012-520-21 BUTTON (AF/TA) FL701 1-517-779-11 INDICATOR TUBE, FLUORESCENT www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 75 – 7-3. CHASSIS SECTION Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 109 106 108 104 107 105 101 102 110 103 104 MG-25E-136 #1 F901 TU1 MG-363X-121 #1 #2 #1 #1 A A * 101 X-3373-616-1 CHASSIS ASSY * 102 3-012-514-01 SHEET, INSULATING * 103 A-3313-768-A MAIN BOARD, COMPLETE 104 3-376-464-11 SCREW (+PTT 2.6X6), GROUND POINT * 105 3-320-882-01 SHEET, DIRECTION * 106 3-012-512-01 BRACKET (CD) 107 A-3313-812-A CD BOARD, COMPLETE * 108 3-012-511-01 BRACKET (2F) * 109 3-012-509-01 BRACKET (1F) 110 3-322-044-01 SPACER, RUBBER F901 1-532-877-11 FUSE (BLADE TYPE) (AUTO FUSE) 10A TU1 A-3282-029-A TUNER UNIT (TUX-006/2(E)) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 76 – 7-4. CD MECHANISM SECTION (1) (MG-363X-121) Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 152 154 161 162 153 159 151 157 161 162 155 156 158 164 165 160 163 166 #8 #8 #7 #7 #7 #8 #9 M903 B B * 151 1-659-836-11 DISC IN SW BOARD * 152 A-3291-816-B CHASSIS (T) SUB ASSY 153 3-931-909-01 SPRING (LR), TENSION 154 X-3371-501-1 LEVER (L) ASSY 155 3-338-737-01 SCREW (2X3), + PS * 156 1-659-837-11 LOAD SW BOARD 157 X-3371-502-1 LEVER (R) ASSY 158 A-3301-203-A ROLLER ASSY 159 3-931-908-01 GUIDE (DISC) 160 3-931-902-03 ARM (ROLLER) 161 3-936-756-01 ROLLER (D) 162 3-321-393-01 WASHER, STOPPER * 163 3-939-139-01 SPACER 164 3-931-916-01 SPRING (RA), TENSION * 165 A-3309-227-A SERVO BOARD, COMPLETE * 166 3-007-530-01 BRACKET (MOTOR) M903 A-3291-676-A MOTOR SUB ASSY, LOADING www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 77 – 7-5. CD MECHANISM SECTION (2) (MG-363X-121) Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 205 204 201 206 207 208 210 212 211 214 209 202 202 202 203 213 207 not supplied #9 C C 201 3-931-893-01 ARM, CHUCKING 202 3-931-897-01 DAMPER (T) 203 3-931-879-02 LEVER (D) * 204 3-913-404-11 RETAINER (DISC) 205 3-931-894-01 BRACKET (CP) 206 3-931-895-01 SPRING (CH), TENSION 207 3-931-898-01 SPRING (FL), COMPRESSION 208 3-019-805-01 SPRING (KF1), TENSION 209 A-3277-802-C CHASSIS (M) ASSY 210 3-931-883-01 SPRING (TR), TENSION 211 3-931-881-01 LEVER (LOCK) 212 3-931-882-02 GEAR (MDL) 213 3-007-537-11 WHEEL (U), WORM 214 3-019-806-01 SPRING (KR1), TENSION www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 78 – Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 7-6. CD MECHANISM SECTION (3) (MG-363X-121) The components identified by mark ! or dotted line with mark. ! are critical for safety. Replace only with part number specified. #6 M901 #9 #8 #8 #5 M902 262 261 259 260 263 258 255 256 254 253 252 257 251 * 251 X-3374-022-1 CHASSIS (OP) (O/S) ASSY 252 3-931-829-01 SPRING (SL), PLATE 253 X-3371-504-1 BASE (DRIVING) ASSY 254 3-931-832-01 GEAR (SL MIDWAY) * 255 1-659-835-12 LIMIT SW BOARD 256 3-338-737-01 SCREW (2X3), + PS 257 1-659-880-11 MOTOR FLEXIBLE BOARD * 258 1-659-834-11 SUB BOARD 259 3-909-607-01 SCREW !260 8-820-010-06 PICK-UP, OPTICAL KSS-521A/K1RP 261 3-931-834-01 SPRING (FEED), PLATE 262 1-659-881-11 PICK-UP FLEXIBLE BOARD 263 A-3291-669-A SHAFT (FEED) ASSY M901 X-3371-664-2 MOTOR ASSY (SPINDLE) M902 A-3291-674-A MOTOR ASSY, SLED www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 79 – Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 7-7. TAPE MECHANISM SECTION (MG-25E-136) 310 309 308 305 304 303 302 306 307 313 311 312 314 315 316 317 301 318 318 HP901 M904 #9 #10 319 301 A-3291-667-A CLUTCH (FR) ASSY * 302 3-019-130-01 LEVER (LDG-A) * 303 3-019-131-01 LEVER (LDG-B) 304 3-020-539-01 SPRING (LD-1), TENSION 305 3-020-540-01 SPRING (LD-2), TENSION 306 3-020-542-01 GEAR (LOADING FT) 307 3-341-753-11 WASHER, POLYETHYLENE 308 3-020-533-01 HOUSING * 309 3-020-532-01 ARM (SUCTION) 310 3-020-534-01 HANGER 311 3-933-346-01 CATCHER 312 3-933-344-01 GUIDE (C) 313 3-014-798-01 SCREW (HEAD), SPECIAL 314 3-364-151-01 WASHER 315 X-3375-625-1 CHASSIS ASSY (E) 316 3-017-302-01 BELT (25) 317 3-936-853-01 FLYWHEEL (F) 318 3-701-437-21 WASHER * 319 3-012-502-01 GUIDE HP901 1-500-157-21 HEAD, MAGNETIC (PLAYBACK) M904 A-3291-665-A MOTOR ASSY, MAIN (CAPSTAN/REEL) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 80 – SECTION 8 ELECTRICAL PARTS LIST CD NOTE: • Due to standardization, replacements in the parts list may be different from the parts specified in the diagrams or the components used on the set. • -XX and -X mean standardized parts, so they may have some difference from the original one. • RESISTORS All resistors are in ohms. METAL:Metal-film resistor. METAL OXIDE: Metal oxide-film resistor. F:nonflammable • Abbreviation G : German model • Items marked “*” are not stocked since they are seldom required for routine service. Some delay should be anticipated when ordering these items. • SEMICONDUCTORS In each case, u : µ, for example: uA.. : µA.. uPA.. : µPA.. uPB.. : µPB.. uPC.. : µPC.. uPD.. : µPD.. • CAPACITORS uF : µF • COILS uH : µH The components identified by mark ! or dotted line with mark. ! are critical for safety. Replace only with part number specified. When indicating parts by reference number, please include the board. Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark A-3313-812-A CD BOARD, COMPLETE ******************* * 3-012-511-01 BRACKET (2F) < CAPACITOR > C401 1-126-157-11 ELECT 10uF 20% 16V C402 1-163-038-00 CERAMIC CHIP 0.1uF 25V C403 1-163-237-11 CERAMIC CHIP 27PF 5% 50V C404 1-163-235-11 CERAMIC CHIP 22PF 5% 50V C405 1-163-241-11 CERAMIC CHIP 39PF 5% 50V C406 1-163-038-00 CERAMIC CHIP 0.1uF 25V C407 1-104-952-11 ELECT 22uF 20% 16V C408 1-163-251-11 CERAMIC CHIP 100PF 5% 50V C409 1-163-251-11 CERAMIC CHIP 100PF 5% 50V C411 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V C412 1-126-157-11 ELECT 10uF 20% 16V C413 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V C421 1-164-232-11 CERAMIC CHIP 0.01uF 50V C431 1-163-038-00 CERAMIC CHIP 0.1uF 25V C432 1-163-038-00 CERAMIC CHIP 0.1uF 25V C433 1-163-038-00 CERAMIC CHIP 0.1uF 25V C434 1-163-038-00 CERAMIC CHIP 0.1uF 25V C441 1-163-243-11 CERAMIC CHIP 47PF 5% 50V C442 1-126-157-11 ELECT 10uF 20% 16V C446 1-164-232-11 CERAMIC CHIP 0.01uF 50V C447 1-126-157-11 ELECT 10uF 20% 16V C451 1-164-005-11 CERAMIC CHIP 0.47uF 25V C452 1-124-234-00 ELECT 22uF 20% 16V C455 1-124-584-00 ELECT 100uF 20% 10V C456 1-163-038-00 CERAMIC CHIP 0.1uF 25V C461 1-164-506-11 CERAMIC CHIP 4.7uF 16V C462 1-124-584-00 ELECT 100uF 20% 10V C463 1-163-038-00 CERAMIC CHIP 0.1uF 25V C464 1-163-038-00 CERAMIC CHIP 0.1uF 25V C465 1-124-584-00 ELECT 100uF 20% 10V C466 1-163-038-00 CERAMIC CHIP 0.1uF 25V C467 1-126-163-11 ELECT 4.7uF 20% 50V C468 1-163-038-00 CERAMIC CHIP 0.1uF 25V C471 1-126-163-11 ELECT 4.7uF 20% 50V C481 1-126-157-11 ELECT 10uF 20% 16V C482 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V C483 1-124-234-00 ELECT 22uF 20% 16V C801 1-126-157-11 ELECT 10uF 20% 16V C802 1-126-157-11 ELECT 10uF 20% 16V C803 1-163-012-00 CERAMIC CHIP 0.0018uF 10% 50V C804 1-126-301-11 ELECT 1uF 20% 50V C805 1-104-944-11 ELECT 3.3uF 20% 50V C806 1-163-005-11 CERAMIC CHIP 470PF 10% 50V C807 1-163-005-11 CERAMIC CHIP 470PF 10% 50V C851 1-126-157-11 ELECT 10uF 20% 16V C852 1-126-157-11 ELECT 10uF 20% 16V C853 1-163-012-00 CERAMIC CHIP 0.0018uF 10% 50V C854 1-126-301-11 ELECT 1uF 20% 50V C855 1-104-944-11 ELECT 3.3uF 20% 50V C856 1-163-005-11 CERAMIC CHIP 470PF 10% 50V C857 1-163-005-11 CERAMIC CHIP 470PF 10% 50V < CONNECTOR > CN401 1-764-617-12 PIN, CONNECTOR (PC BOARD) 30P CN402 1-770-405-11 CONNECTOR, BOARD TO BOARD 8P * CN403 1-506-999-11 PIN, CONNECTOR (PC BOARD) 3P * CN404 1-564-728-11 PIN, CONNECTOR (SMALL TYPE) 12P * CN802 1-564-724-11 PIN, CONNECTOR (SMALL TYPE) 8P < JACK > CN803 1-774-699-12 JACK, PIN 4P (LINE OUT) < DIODE > D451 8-719-404-49 DIODE MA111 D461 8-719-422-49 DIODE MA8056-L D462 8-719-422-94 DIODE MA8091-L D471 8-719-423-10 DIODE MA8100-M-TX D481 8-719-421-18 DIODE MA8033-L-TX D482 8-719-404-49 DIODE MA111 D483 8-719-200-82 DIODE 11ES2 D491 8-719-404-49 DIODE MA111 D801 8-719-421-36 DIODE MA8036-L D851 8-719-421-36 DIODE MA8036-L < IC > IC401 8-759-537-65 IC uPD78054GC-484-3B9 IC801 8-759-464-81 IC PCM1717E-ST2 IC802 8-759-537-11 IC SM5852FS-E2 < JUMPER RESISTOR > JC405 1-216-295-00 SHORT 0 JC406 1-216-295-00 SHORT 0 JC407 1-216-295-00 SHORT 0 JC408 1-216-295-00 SHORT 0 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 81 – Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark CD DISC IN SW KEY JC410 1-216-295-00 SHORT 0 JC412 1-216-295-00 SHORT 0 JC451 1-216-296-00 SHORT 0 JC453 1-216-296-00 SHORT 0 JC454 1-216-296-00 SHORT 0 JC455 1-216-296-00 SHORT 0 JC456 1-216-296-00 SHORT 0 JC457 1-216-295-00 SHORT 0 < COIL > L401 1-410-513-11 INDUCTOR 22uH L402 1-410-513-11 INDUCTOR 22uH L411 1-410-513-11 INDUCTOR 22uH L455 1-410-513-11 INDUCTOR 22uH < TRANSISTOR > Q401 1-801-806-11 TRANSISTOR DTC144EKA-T146 Q451 8-729-424-12 TRANSISTOR UN2112 Q461 1-801-806-11 TRANSISTOR DTC144EKA-T146 Q462 8-729-019-00 TRANSISTOR 2SD2394-G Q463 8-729-020-67 TRANSISTOR XN1A312-TX Q464 8-729-019-00 TRANSISTOR 2SD2394-G Q465 8-729-020-67 TRANSISTOR XN1A312-TX Q471 8-729-106-60 TRANSISTOR 2SB1115A Q472 8-729-421-22 TRANSISTOR UN2211 Q473 8-729-019-00 TRANSISTOR 2SD2394-G Q474 8-729-020-67 TRANSISTOR XN1A312-TX Q481 8-729-019-00 TRANSISTOR 2SD2394-G Q482 8-729-106-60 TRANSISTOR 2SB1115A Q483 8-729-230-49 TRANSISTOR 2SC2712-YG Q491 8-729-230-49 TRANSISTOR 2SC2712-YG Q801 8-729-920-21 TRANSISTOR DTC314TKH04 Q802 8-729-920-21 TRANSISTOR DTC314TKH04 Q851 8-729-920-21 TRANSISTOR DTC314TKH04 Q852 8-729-920-21 TRANSISTOR DTC314TKH04 < RESISTOR > R401 1-216-295-00 SHORT 0 R402 1-216-037-00 METAL CHIP 330 5% 1/10W R403 1-216-097-00 RES,CHIP 100K 5% 1/10W R411 1-216-025-00 RES,CHIP 100 5% 1/10W R412 1-216-025-00 RES,CHIP 100 5% 1/10W R413 1-216-025-00 RES,CHIP 100 5% 1/10W R414 1-216-037-00 METAL CHIP 330 5% 1/10W R431 1-249-437-11 CARBON 47K 5% 1/4W R432 1-247-807-11 CARBON 100 5% 1/4W R433 1-247-807-11 CARBON 100 5% 1/4W R434 1-247-807-11 CARBON 100 5% 1/4W R441 1-216-089-00 RES,CHIP 47K 5% 1/10W R442 1-216-097-00 RES,CHIP 100K 5% 1/10W R444 1-249-437-11 CARBON 47K 5% 1/4W R445 1-216-089-00 RES,CHIP 47K 5% 1/10W R446 1-216-105-00 RES,CHIP 220K 5% 1/10W R447 1-216-001-00 METAL CHIP 10 5% 1/10W R448 1-216-089-00 RES,CHIP 47K 5% 1/10W R451 1-216-017-00 RES,CHIP 47 5% 1/10W R461 1-216-182-00 RES,CHIP 220 5% 1/8W R462 1-216-188-00 RES,CHIP 390 5% 1/8W R471 1-216-206-00 RES,CHIP 2.2K 5% 1/8W R472 1-216-079-00 METAL CHIP 18K 5% 1/10W R473 1-216-079-00 METAL CHIP 18K 5% 1/10W R474 1-216-190-00 RES,CHIP 470 5% 1/8W R475 1-216-190-00 RES,CHIP 470 5% 1/8W R481 1-249-417-11 CARBON 1K 5% 1/4W R482 1-216-206-00 RES,CHIP 2.2K 5% 1/8W R483 1-216-190-00 RES,CHIP 470 5% 1/8W R484 1-216-049-11 RES,CHIP 1K 5% 1/10W R485 1-216-049-11 RES,CHIP 1K 5% 1/10W R491 1-216-089-00 RES,CHIP 47K 5% 1/10W R492 1-216-097-00 RES,CHIP 100K 5% 1/10W R801 1-247-815-11 CARBON 220 5% 1/4W R802 1-247-815-11 CARBON 220 5% 1/4W R803 1-216-081-00 METAL CHIP 22K 5% 1/10W R804 1-216-081-00 METAL CHIP 22K 5% 1/10W R805 1-216-049-11 RES,CHIP 1K 5% 1/10W R851 1-216-033-00 METAL CHIP 220 5% 1/10W R852 1-216-033-00 METAL CHIP 220 5% 1/10W R853 1-216-081-00 METAL CHIP 22K 5% 1/10W R854 1-216-081-00 METAL CHIP 22K 5% 1/10W R855 1-216-049-11 RES,CHIP 1K 5% 1/10W < VIBRATOR > X401 1-579-280-31 VIBRATOR, CRYSTAL (16.9344MHz) X402 1-760-489-11 VIBRATOR, CERAMIC (5MHz) ************************************************************* * 1-659-836-11 DISC IN SW BOARD **************** < SWITCH > SW1 1-572-288-11 SWITCH, PUSH (DISC IN) SW2 1-572-288-11 SWITCH, PUSH (SELF) ************************************************************* * A-3313-770-A KEY BOARD, COMPLETE ******************** < CAPACITOR > C701 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V C702 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V C703 1-163-110-00 CERAMIC CHIP 51PF 5% 50V C704 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V C705 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V < CONNECTOR > CN701 1-770-983-11 SOCKET, CONNECTOR 8P www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 82 – Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark KEY CN702 1-784-909-11 CONNECTOR, BOARD TO BOARD 16P < DIODE > D701 8-719-977-03 DIODE DTZ5.6B D706 8-719-404-49 DIODE MA111 D713 8-719-975-06 LED CL-70G-CD (6 (CD)) D714 8-719-975-06 LED CL-70G-CD (CD/MD) D715 8-719-975-06 LED CL-70G-CD (TAPE *) D716 8-719-975-06 LED CL-70G-CD (TUNER) D730 8-719-975-06 LED CL-70G-CD (TAPE WINDOW) D731 8-719-975-06 LED CL-70G-CD (CD WINDOW) D732 8-719-059-80 LED CL-170TY-CD-T (DIGITAL) D733 8-719-059-80 LED CL-170TY-CD-T (D-BASS) D734 8-719-059-80 LED CL-170TY-CD-T (TAPE IN) D735 8-719-059-80 LED CL-170TY-CD-T (CD IN) D736 8-719-052-72 LED CL-220HR-C (n) D737 8-719-052-72 LED CL-220HR-C (P MODE) D738 8-719-052-72 LED CL-220HR-C (SET UP) D739 8-719-052-72 LED CL-220HR-C (N) D740 8-719-052-72 LED CL-220HR-C (ENTER) D741 8-719-052-72 LED CL-220HR-C (SHUF) D742 8-719-052-72 LED CL-220HR-C (REP) < FLUORESCENT INDICATOR > FL701 1-517-779-11 INDICATOR TUBE, FLUORESCENT < IC > IC701 8-759-528-30 IC LC75750EHS IC702 8-759-267-27 IC BU2092F < SWITCH > LSW701 1-762-618-11 SWITCH, KEY BOARD (WITH LED) (OFF) LSW702 1-762-618-11 SWITCH, KEY BOARD (WITH LED) (6 (TAPE)) LSW703 1-762-618-11 SWITCH, KEY BOARD (WITH LED) (10) LSW704 1-762-618-11 SWITCH, KEY BOARD (WITH LED) (9) LSW705 1-762-618-11 SWITCH, KEY BOARD (WITH LED) (8) LSW706 1-762-618-11 SWITCH, KEY BOARD (WITH LED) (7) LSW707 1-762-618-11 SWITCH, KEY BOARD (WITH LED) (6) LSW708 1-762-618-11 SWITCH, KEY BOARD (WITH LED) (5) LSW709 1-762-618-11 SWITCH, KEY BOARD (WITH LED) (4) LSW710 1-762-618-11 SWITCH, KEY BOARD (WITH LED) (3) LSW711 1-762-618-11 SWITCH, KEY BOARD (WITH LED) (2) LSW712 1-762-618-11 SWITCH, KEY BOARD (WITH LED) (1) LSW717 1-762-618-11 SWITCH, KEY BOARD (WITH LED) (AF/TA) LSW718 1-762-618-11 SWITCH, KEY BOARD (WITH LED) (SHIFT) LSW719 1-762-618-11 SWITCH, KEY BOARD (WITH LED) (+ ) + (SEEK/AMS)) LSW720 1-762-618-11 SWITCH, KEY BOARD (WITH LED) (- 0 = (SEEK/AMS)) LSW721 1-762-618-11 SWITCH, KEY BOARD (WITH LED) (PTY/FILE) LSW722 1-762-618-11 SWITCH, KEY BOARD (WITH LED) (SOUND) LSW723 1-762-618-11 SWITCH, KEY BOARD (WITH LED) (DSPL) < TRANSISTOR > Q701 8-729-230-49 TRANSISTOR 2SC2712-YG Q702 8-729-904-48 TRANSISTOR DTB113EK Q703 8-729-904-48 TRANSISTOR DTB113EK Q704 8-729-904-48 TRANSISTOR DTB113EK Q705 8-729-904-48 TRANSISTOR DTB113EK < RESISTOR > R701 1-216-041-00 METAL CHIP 470 5% 1/10W R702 1-216-075-00 METAL CHIP 12K 5% 1/10W R705 1-208-826-11 RES,CHIP 68K 2% 1/10W R706 1-208-518-61 RES,CHIP 22K 2% 1/10W R707 1-208-462-61 RES,CHIP 10K 2% 1/10W R708 1-208-453-61 RES,CHIP 4.7K 2% 1/10W R715 1-216-045-00 METAL CHIP 680 5% 1/10W R716 1-216-045-00 METAL CHIP 680 5% 1/10W R717 1-216-045-00 METAL CHIP 680 5% 1/10W R718 1-216-045-00 METAL CHIP 680 5% 1/10W R719 1-216-045-00 METAL CHIP 680 5% 1/10W R720 1-216-045-00 METAL CHIP 680 5% 1/10W R721 1-216-045-00 METAL CHIP 680 5% 1/10W R722 1-216-045-00 METAL CHIP 680 5% 1/10W R723 1-216-045-00 METAL CHIP 680 5% 1/10W R724 1-216-045-00 METAL CHIP 680 5% 1/10W R725 1-216-045-00 METAL CHIP 680 5% 1/10W R726 1-216-045-00 METAL CHIP 680 5% 1/10W R727 1-216-045-00 METAL CHIP 680 5% 1/10W R728 1-216-045-00 METAL CHIP 680 5% 1/10W R730 1-216-025-00 RES,CHIP 100 5% 1/10W R731 1-216-025-00 RES,CHIP 100 5% 1/10W R732 1-216-192-00 METAL CHIP 560 5% 1/8W R733 1-216-192-00 METAL CHIP 560 5% 1/8W R734 1-216-192-00 METAL CHIP 560 5% 1/8W R735 1-216-192-00 METAL CHIP 560 5% 1/8W R736 1-216-192-00 METAL CHIP 560 5% 1/8W R737 1-216-192-00 METAL CHIP 560 5% 1/8W R738 1-216-192-00 METAL CHIP 560 5% 1/8W R739 1-216-192-00 METAL CHIP 560 5% 1/8W R740 1-216-647-11 METAL CHIP 680 0.5% 1/10W R741 1-216-647-11 METAL CHIP 680 0.5% 1/10W R742 1-216-647-11 METAL CHIP 680 0.5% 1/10W R743 1-208-437-61 RES,CHIP 1K 2% 1/10W R744 1-208-441-61 RES,CHIP 1.5K 2% 1/10W R745 1-208-441-61 RES,CHIP 1.5K 2% 1/10W R746 1-216-659-11 METAL CHIP 2.2K 0.5% 1/10W R747 1-208-449-61 RES,CHIP 3.3K 2% 1/10W R748 1-208-453-61 RES,CHIP 4.7K 2% 1/10W R749 1-216-671-11 METAL CHIP 6.8K 0.5% 1/10W R750 1-208-462-61 RES,CHIP 10K 2% 1/10W R751 1-216-647-11 METAL CHIP 680 0.5% 1/10W R752 1-216-647-11 METAL CHIP 680 0.5% 1/10W R753 1-216-647-11 METAL CHIP 680 0.5% 1/10W R754 1-208-437-61 RES,CHIP 1K 2% 1/10W www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 83 – Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark MAIN LIMIT SW LOAD SW KEY R755 1-208-441-61 RES,CHIP 1.5K 2% 1/10W R756 1-208-441-61 RES,CHIP 1.5K 2% 1/10W R757 1-216-659-11 METAL CHIP 2.2K 0.5% 1/10W R758 1-208-449-61 RES,CHIP 3.3K 2% 1/10W R759 1-208-453-61 RES,CHIP 4.7K 2% 1/10W R760 1-216-671-11 METAL CHIP 6.8K 0.5% 1/10W R774 1-216-025-00 RES,CHIP 100 5% 1/10W R775 1-216-025-00 RES,CHIP 100 5% 1/10W R776 1-216-031-00 METAL CHIP 180 5% 1/10W R777 1-216-031-00 METAL CHIP 180 5% 1/10W R778 1-216-031-00 METAL CHIP 180 5% 1/10W < SWITCH > SW700 1-762-937-11 SWITCH, ROTARY (D-BASS) SW701 1-771-027-11 SWITCH, KEYBOARD (WITH LED) (RESET) SW702 1-475-216-11 ENCODER, ROTARY SW713 1-771-027-11 SWITCH, KEYBOARD (WITH LED) (6 (CD)) SW714 1-771-027-11 SWITCH, KEYBOARD (WITH LED) (CD/MD) SW715 1-771-027-11 SWITCH, KEYBOARD (WITH LED) (TAPE *) SW716 1-771-027-11 SWITCH, KEYBOARD (WITH LED) (TUNER) ************************************************************* * 1-659-835-12 LIMIT SW BOARD *************** < SWITCH > SW3 1-572-688-11 SWITCH, PUSH (1 KEY) (LIMIT) ************************************************************* * 1-659-837-11 LOAD SW BOARD *************** < SWITCH > SW4 1-572-288-11 SWITCH, PUSH (DOWN) ************************************************************* * A-3313-768-A MAIN BOARD, COMPLETE (INCLUDING SW BOARD) ********************* * 3-012-509-01 BRACKET (1F) < BUZZER > BZ591 1-504-920-11 BUZZER < CAPACITOR > C1 1-163-235-11 CERAMIC CHIP 22PF 5% 50V C2 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V C3 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V C4 1-124-584-00 ELECT 100uF 20% 10V C5 1-124-584-00 ELECT 100uF 20% 10V C6 1-124-584-00 ELECT 100uF 20% 10V C7 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V C8 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V C11 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V C12 1-164-232-11 CERAMIC CHIP 0.01uF 50V C13 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V C31 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V C41 1-137-370-11 FILM 0.01uF 5% 50V C42 1-137-364-11 FILM 0.001uF 5% 50V C43 1-115-330-11 FILM 0.22uF 5% 50V C44 1-115-326-11 FILM 0.1uF 5% 50V C45 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V C46 1-137-370-11 FILM 0.01uF 5% 50V C47 1-137-366-11 FILM 0.0022uF 5% 50V C48 1-164-232-11 CERAMIC CHIP 0.01uF 50V C51 1-163-251-11 CERAMIC CHIP 100PF 5% 50V C52 1-164-232-11 CERAMIC CHIP 0.01uF 50V C53 1-163-251-11 CERAMIC CHIP 100PF 5% 50V C54 1-163-251-11 CERAMIC CHIP 100PF 5% 50V C55 1-124-229-00 ELECT 33uF 20% 10V C56 1-164-232-11 CERAMIC CHIP 0.01uF 50V C57 1-163-235-11 CERAMIC CHIP 22PF 5% 50V C58 1-163-241-11 CERAMIC CHIP 39PF 5% 50V C59 1-163-005-11 CERAMIC CHIP 470PF 10% 50V C60 1-163-005-11 CERAMIC CHIP 470PF 10% 50V C71 1-164-232-11 CERAMIC CHIP 0.01uF 50V C72 1-124-234-00 ELECT 22uF 20% 16V C73 1-124-584-00 ELECT 100uF 20% 10V C74 1-164-232-11 CERAMIC CHIP 0.01uF 50V C81 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V C83 1-163-237-11 CERAMIC CHIP 27PF 5% 50V C84 1-163-237-11 CERAMIC CHIP 27PF 5% 50V C85 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V C89 1-163-135-00 CERAMIC CHIP 560PF 5% 50V C90 1-164-505-11 CERAMIC CHIP 2.2uF 16V C91 1-163-263-11 CERAMIC CHIP 330PF 5% 50V C92 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V C93 1-163-251-11 CERAMIC CHIP 100PF 5% 50V C94 1-163-251-11 CERAMIC CHIP 100PF 5% 50V C96 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 100V C101 1-163-263-11 CERAMIC CHIP 330PF 5% 50V C102 1-163-263-11 CERAMIC CHIP 330PF 5% 50V C103 1-163-251-11 CERAMIC CHIP 100PF 5% 50V C104 1-163-251-11 CERAMIC CHIP 100PF 5% 50V C105 1-163-251-11 CERAMIC CHIP 100PF 5% 50V C106 1-164-232-11 CERAMIC CHIP 0.01uF 50V C107 1-126-159-11 ELECT 0.47uF 20% 50V C108 1-126-163-11 ELECT 4.7uF 20% 50V C152 1-163-020-00 CERAMIC CHIP 0.0082uF 10% 50V C153 1-164-489-11 CERAMIC CHIP 0.22uF 10% 16V C154 1-164-489-11 CERAMIC CHIP 0.22uF 10% 16V C155 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V C163 1-124-257-00 ELECT 2.2uF 20% 50V C171 1-126-301-11 ELECT 1uF 20% 50V C172 1-126-157-11 ELECT 10uF 20% 16V C173 1-115-419-11 CERAMIC CHIP 3300PF 5% 25V C174 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 84 – Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark MAIN C175 1-126-157-11 ELECT 10uF 20% 16V C176 1-164-492-11 CERAMIC CHIP 0.15uF 10% 16V C177 1-164-492-11 CERAMIC CHIP 0.15uF 10% 16V C178 1-126-157-11 ELECT 10uF 20% 16V C181 1-126-157-11 ELECT 10uF 20% 16V C182 1-126-157-11 ELECT 10uF 20% 16V C183 1-164-506-11 CERAMIC CHIP 4.7uF 16V C184 1-164-506-11 CERAMIC CHIP 4.7uF 16V C191 1-163-259-11 CERAMIC CHIP 220PF 5% 50V C192 1-163-259-11 CERAMIC CHIP 220PF 5% 50V C201 1-163-263-11 CERAMIC CHIP 330PF 5% 50V C202 1-163-263-11 CERAMIC CHIP 330PF 5% 50V C203 1-163-251-11 CERAMIC CHIP 100PF 5% 50V C204 1-163-251-11 CERAMIC CHIP 100PF 5% 50V C205 1-163-251-11 CERAMIC CHIP 100PF 5% 50V C206 1-164-232-11 CERAMIC CHIP 0.01uF 50V C207 1-126-159-11 ELECT 0.47uF 20% 50V C208 1-126-163-11 ELECT 4.7uF 20% 50V C252 1-163-020-00 CERAMIC CHIP 0.0082uF 10% 50V C253 1-164-489-11 CERAMIC CHIP 0.22uF 10% 16V C254 1-164-489-11 CERAMIC CHIP 0.22uF 10% 16V C255 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V C263 1-124-257-00 ELECT 2.2uF 20% 50V C271 1-126-301-11 ELECT 1uF 20% 50V C272 1-126-157-11 ELECT 10uF 20% 16V C273 1-115-419-11 CERAMIC CHIP 3300PF 5% 25V C274 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V C275 1-126-157-11 ELECT 10uF 20% 16V C276 1-164-492-11 CERAMIC CHIP 0.15uF 10% 16V C277 1-164-492-11 CERAMIC CHIP 0.15uF 10% 16V C278 1-126-157-11 ELECT 10uF 20% 16V C281 1-126-157-11 ELECT 10uF 20% 16V C282 1-126-157-11 ELECT 10uF 20% 16V C283 1-164-506-11 CERAMIC CHIP 4.7uF 16V C284 1-164-506-11 CERAMIC CHIP 4.7uF 16V C291 1-163-259-11 CERAMIC CHIP 220PF 5% 50V C292 1-163-259-11 CERAMIC CHIP 220PF 5% 50V C301 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V C302 1-124-584-00 ELECT 100uF 20% 10V C303 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V C304 1-124-584-00 ELECT 100uF 20% 10V C305 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V C306 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V C308 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V C309 1-163-809-11 CERAMIC CHIP 0.047uF 10% 25V C310 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V C311 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V C313 1-126-163-11 ELECT 4.7uF 20% 50V C321 1-126-941-11 ELECT 470uF 20% 25V C322 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V C323 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V C324 1-126-157-11 ELECT 10uF 20% 16V C325 1-164-489-11 CERAMIC CHIP 0.22uF 10% 16V C326 1-124-234-00 ELECT 22uF 20% 16V C351 1-163-809-11 CERAMIC CHIP 0.047uF 10% 25V C352 1-163-809-11 CERAMIC CHIP 0.047uF 10% 25V C353 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V C354 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V C362 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V C363 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V C365 1-163-220-11 CERAMIC CHIP 3PF 0.25PF 50V C371 1-163-038-00 CERAMIC CHIP 0.1uF 25V C372 1-124-584-00 ELECT 100uF 20% 10V C373 1-124-234-00 ELECT 22uF 20% 16V C374 1-163-038-00 CERAMIC CHIP 0.1uF 25V C391 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V C392 1-126-157-11 ELECT 10uF 20% 16V C393 1-111-233-11 ELECT 5600uF 20% 16V C394 1-164-506-11 CERAMIC CHIP 4.7uF 16V C501 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V C502 1-164-232-11 CERAMIC CHIP 0.01uF 50V C515 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V C516 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V C517 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V C528 1-163-251-11 CERAMIC CHIP 100PF 5% 50V C529 1-163-102-11 CERAMIC CHIP 24PF 5% 50V C530 1-163-235-11 CERAMIC CHIP 22PF 5% 50V C531 1-164-232-11 CERAMIC CHIP 0.01uF 50V C532 1-164-232-11 CERAMIC CHIP 0.01uF 50V C533 1-164-232-11 CERAMIC CHIP 0.01uF 50V C541 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V C542 1-124-584-00 ELECT 100uF 20% 10V C551 1-126-157-11 ELECT 10uF 20% 16V C552 1-126-157-11 ELECT 10uF 20% 16V C561 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V C562 1-164-489-11 CERAMIC CHIP 0.22uF 10% 16V C563 1-125-701-11 DOUBLE LAYERS 0.047F 5.5V C564 1-124-584-00 ELECT 100uF 20% 10V C565 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V C581 1-163-005-11 CERAMIC CHIP 470PF 10% 50V C901 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V C902 1-115-326-11 FILM 0.1uF 5% 50V C903 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V C904 1-163-275-11 CERAMIC CHIP 0.001uF 5% 50V C905 1-163-275-11 CERAMIC CHIP 0.001uF 5% 50V C906 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V C907 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V C908 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V C909 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V C911 1-126-163-11 ELECT 4.7uF 20% 50V C921 1-126-157-11 ELECT 10uF 20% 16V C922 1-126-157-11 ELECT 10uF 20% 16V C923 1-126-157-11 ELECT 10uF 20% 16V C924 1-124-589-11 ELECT 47uF 20% 16V C925 1-124-234-00 ELECT 22uF 20% 16V C926 1-164-005-11 CERAMIC CHIP 0.47uF 25V www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 85 – Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark MAIN C931 1-124-242-00 ELECT 33uF 20% 25V C932 1-124-229-00 ELECT 33uF 20% 10V C933 1-124-229-00 ELECT 33uF 20% 10V C934 1-126-157-11 ELECT 10uF 20% 16V C935 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V C936 1-126-157-11 ELECT 10uF 20% 16V C937 1-163-251-11 CERAMIC CHIP 100PF 5% 50V C938 1-124-234-00 ELECT 22uF 20% 16V C939 1-126-157-11 ELECT 10uF 20% 16V C941 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V C942 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V C943 1-126-157-11 ELECT 10uF 20% 16V C951 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V C954 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V C971 1-126-163-11 ELECT 4.7uF 20% 50V < CONNECTOR > CN301 1-766-260-11 CONNECTOR, FFC/FPC (ZIF) 7P CN302 1-778-965-21 CONNECTOR 12P CN303 1-779-806-21 CONNECTOR 8P CN304 1-774-698-11 JACK, PIN 2P (BUS AUDIO IN) CN321 1-566-010-11 PIN, CONNECTOR (PC BOARD) 13P CN501 1-784-908-11 CONNECTOR, BOARD TO BOARD 16P CN900 1-774-701-11 PIN, CONNECTOR 16P * CN901 1-506-985-11 PIN, CONNECTOR (PC BOARD) 3P CN951 1-580-907-31 PLUG, CONNECTOR (BUS CONTROL IN) < DISCHARGE GAP > CP1 1-519-504-11 GAP, DISCHARGE < DIODE > D1 8-719-040-04 DIODE MA721WK-(TX) D71 8-719-977-03 DIODE DTZ5.6B D181 8-719-421-36 DIODE MA8036-L D191 8-719-048-98 DIODE RB160L-40TE25 D192 8-719-048-98 DIODE RB160L-40TE25 D193 8-719-048-98 DIODE RB160L-40TE25 D194 8-719-048-98 DIODE RB160L-40TE25 D281 8-719-421-36 DIODE MA8036-L D291 8-719-048-98 DIODE RB160L-40TE25 D292 8-719-048-98 DIODE RB160L-40TE25 D293 8-719-048-98 DIODE RB160L-40TE25 D294 8-719-048-98 DIODE RB160L-40TE25 D301 8-719-404-49 DIODE MA111 D321 8-719-200-82 DIODE 11ES2 D322 8-719-422-97 DIODE MA8091-M D323 8-719-404-49 DIODE MA111 D324 8-719-404-49 DIODE MA111 D361 8-719-404-49 DIODE MA111 D561 8-719-404-49 DIODE MA111 D562 8-719-404-49 DIODE MA111 D563 8-719-067-56 DIODE MA112-TX D564 8-719-067-56 DIODE MA112-TX D565 8-719-400-20 DIODE MA152WA D566 8-719-977-12 DIODE DTZ6.8B D567 8-719-977-12 DIODE DTZ6.8B D568 8-719-404-49 DIODE MA111 D569 8-719-067-56 DIODE MA112-TX D571 8-719-977-12 DIODE DTZ6.8B D581 8-719-977-12 DIODE DTZ6.8B D582 8-719-977-12 DIODE DTZ6.8B D901 8-719-049-38 DIODE 1N5404TU D902 8-719-977-04 DIODE DTZ5.6C D903 8-719-048-98 DIODE RB160L-40TE25 D904 8-719-048-98 DIODE RB160L-40TE25 D905 8-719-057-80 DIODE MA8160-M-TX D906 8-719-057-80 DIODE MA8160-M-TX D907 8-719-801-78 DIODE 1SS184 D908 8-719-422-76 DIODE MA8075-M D910 8-719-048-98 DIODE RB160L-40TE25 D921 8-719-404-49 DIODE MA111 D923 8-719-017-91 DIODE MA8160 D924 8-719-404-49 DIODE MA111 D941 8-719-067-56 DIODE MA112-TX D951 8-719-057-80 DIODE MA8160-M-TX D952 8-719-057-80 DIODE MA8160-M-TX D953 8-719-057-80 DIODE MA8160-M-TX D954 8-719-017-62 DIODE MA8068-L-TX D955 8-719-017-91 DIODE MA8160 D956 8-719-048-98 DIODE RB160L-40TE25 D971 8-719-801-78 DIODE 1SS184 D972 8-719-105-99 DIODE RD6.2M-B1 < FUSE > F901 1-532-877-11 FUSE (BLADE TYPE) (AUTO FUSE) 10A < IC > IC41 8-759-184-64 IC TC4W66FU IC51 8-759-448-85 IC BU2624FV-E2 IC81 8-759-492-59 IC SAA6588T-118 IC301 8-752-079-79 IC CXA2510AQ-T4 IC302 8-759-487-82 IC LC75374E IC303 8-759-391-88 IC BU4066BCFV-E2 IC306 8-759-490-48 IC HA13158 IC321 8-759-823-87 IC LB1638M IC501 8-759-537-66 IC MB90574PFV-G-118-BND IC561 8-759-461-86 IC RH5VL40AA-T1 IC562 8-759-495-76 IC RN5VD33AA-TL IC901 8-759-347-49 IC BA3918-V2 IC941 8-759-496-74 IC TA78DL06S IC951 8-759-449-89 IC BA8270F-E2 < JACK > J1 1-764-808-14 JACK (ANTENNA) J501 1-566-822-41 JACK (REMOTE IN) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 86 – Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark MAIN < JUMPER RESISTOR > JR3 1-216-295-00 SHORT 0 JR5 1-216-295-00 SHORT 0 < COIL > L51 1-410-513-11 INDUCTOR 22uH L81 1-410-513-11 INDUCTOR 22uH L500 1-410-509-11 INDUCTOR 10uH L901 1-411-669-12 COIL, CHOKE < EARTH TERMINAL > * LUG1 1-537-738-21 TERMINAL, EARTH * LUG2 1-537-738-21 TERMINAL, EARTH * LUG3 1-537-738-21 TERMINAL, EARTH < THERMISTOR (POSITIVE) > PS951 1-801-792-21 THERMISTOR, POSITIVE < TRANSISTOR > Q31 8-729-230-49 TRANSISTOR 2SC2712-YG Q41 8-729-021-94 FET 2SK1657-T1B Q61 8-729-421-22 TRANSISTOR UN2211 Q71 8-729-230-49 TRANSISTOR 2SC2712-YG Q81 8-729-020-67 TRANSISTOR XN1A312-TX Q82 8-729-230-49 TRANSISTOR 2SC2712-YG Q151 8-729-920-21 TRANSISTOR DTC314TKH04 Q181 8-729-920-21 TRANSISTOR DTC314TKH04 Q182 8-729-920-21 TRANSISTOR DTC314TKH04 Q251 8-729-920-21 TRANSISTOR DTC314TKH04 Q281 8-729-920-21 TRANSISTOR DTC314TKH04 Q282 8-729-920-21 TRANSISTOR DTC314TKH04 Q321 8-729-807-12 TRANSISTOR 2SD1802-S Q322 8-729-424-08 TRANSISTOR UN2111 Q323 8-729-421-22 TRANSISTOR UN2211 Q324 8-729-106-60 TRANSISTOR 2SB1115A Q325 8-729-421-22 TRANSISTOR UN2211 Q351 8-729-421-22 TRANSISTOR UN2211 Q352 8-729-230-49 TRANSISTOR 2SC2712-YG Q561 8-729-424-08 TRANSISTOR UN2111 Q562 8-729-424-08 TRANSISTOR UN2111 Q591 8-729-421-22 TRANSISTOR UN2211 Q901 8-729-230-49 TRANSISTOR 2SC2712-YG Q902 8-729-230-49 TRANSISTOR 2SC2712-YG Q903 8-729-021-93 TRANSISTOR UPA502T-T1 Q921 8-729-424-08 TRANSISTOR UN2111 Q922 8-729-421-22 TRANSISTOR UN2211 Q923 8-729-421-22 TRANSISTOR UN2211 Q924 8-729-424-12 TRANSISTOR UN2112 Q951 8-729-216-22 TRANSISTOR 2SA1162-G Q952 8-729-421-22 TRANSISTOR UN2211 Q971 8-729-230-49 TRANSISTOR 2SC2712-YG < RESISTOR > R1 1-216-295-00 SHORT 0 R2 1-216-049-11 RES,CHIP 1K 5% 1/10W R3 1-216-037-00 METAL CHIP 330 5% 1/10W R11 1-216-073-00 METAL CHIP 10K 5% 1/10W R12 1-216-065-00 RES,CHIP 4.7K 5% 1/10W R13 1-216-073-00 METAL CHIP 10K 5% 1/10W R14 1-216-061-00 METAL CHIP 3.3K 5% 1/10W R15 1-216-037-00 METAL CHIP 330 5% 1/10W R16 1-216-298-00 METAL CHIP 2.2 5% 1/10W R17 1-216-298-00 METAL CHIP 2.2 5% 1/10W R18 1-216-073-00 METAL CHIP 10K 5% 1/10W R31 1-216-119-00 METAL CHIP 820K 5% 1/10W R32 1-216-073-00 METAL CHIP 10K 5% 1/10W R41 1-216-073-00 METAL CHIP 10K 5% 1/10W R42 1-216-065-00 RES,CHIP 4.7K 5% 1/10W R43 1-216-089-00 RES,CHIP 47K 5% 1/10W R44 1-216-089-00 RES,CHIP 47K 5% 1/10W R45 1-216-049-11 RES,CHIP 1K 5% 1/10W R46 1-216-081-00 METAL CHIP 22K 5% 1/10W R51 1-216-295-00 SHORT 0 R52 1-216-057-00 METAL CHIP 2.2K 5% 1/10W R53 1-216-073-00 METAL CHIP 10K 5% 1/10W R71 1-216-057-00 METAL CHIP 2.2K 5% 1/10W R81 1-216-113-00 METAL CHIP 470K 5% 1/10W R82 1-216-049-11 RES,CHIP 1K 5% 1/10W R83 1-216-071-00 METAL CHIP 8.2K 5% 1/10W R85 1-216-041-00 METAL CHIP 470 5% 1/10W R86 1-216-035-00 METAL CHIP 270 5% 1/10W R87 1-216-035-00 METAL CHIP 270 5% 1/10W R88 1-216-001-00 METAL CHIP 10 5% 1/10W R89 1-216-097-00 RES,CHIP 100K 5% 1/10W R90 1-216-097-00 RES,CHIP 100K 5% 1/10W R91 1-216-001-00 METAL CHIP 10 5% 1/10W R101 1-208-534-61 RES,CHIP 100K 2% 1/10W R102 1-208-534-61 RES,CHIP 100K 2% 1/10W R103 1-216-027-00 METAL CHIP 120 5% 1/10W R104 1-208-812-11 RES,CHIP 18K 2% 1/10W R105 1-216-677-11 METAL CHIP 12K 0.5% 1/10W R106 1-218-764-11 RES,CHIP 330K 2% 1/10W R107 1-216-077-00 METAL CHIP 15K 5% 1/10W R150 1-216-295-00 SHORT 0 R151 1-216-069-00 METAL CHIP 6.8K 5% 1/10W R152 1-216-081-00 METAL CHIP 22K 5% 1/10W R153 1-216-097-00 RES,CHIP 100K 5% 1/10W R167 1-216-073-00 METAL CHIP 10K 5% 1/10W R168 1-216-049-11 RES,CHIP 1K 5% 1/10W R171 1-208-449-41 RES,CHIP 3.3K 2% 1/10W R181 1-216-033-00 METAL CHIP 220 5% 1/10W R184 1-216-033-00 METAL CHIP 220 5% 1/10W R185 1-216-033-00 METAL CHIP 220 5% 1/10W R186 1-216-081-00 METAL CHIP 22K 5% 1/10W www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 87 – Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark MAIN R187 1-216-081-00 METAL CHIP 22K 5% 1/10W R188 1-216-033-00 METAL CHIP 220 5% 1/10W R191 1-216-085-00 METAL CHIP 33K 5% 1/10W R192 1-216-085-00 METAL CHIP 33K 5% 1/10W R201 1-208-534-61 RES,CHIP 100K 2% 1/10W R202 1-208-534-61 RES,CHIP 100K 2% 1/10W R203 1-216-027-00 METAL CHIP 120 5% 1/10W R204 1-208-812-11 RES,CHIP 18K 2% 1/10W R205 1-216-677-11 METAL CHIP 12K 0.5% 1/10W R206 1-218-764-11 RES,CHIP 330K 2% 1/10W R207 1-216-077-00 METAL CHIP 15K 5% 1/10W R250 1-216-295-00 SHORT 0 R251 1-216-069-00 METAL CHIP 6.8K 5% 1/10W R252 1-216-081-00 METAL CHIP 22K 5% 1/10W R253 1-216-097-00 RES,CHIP 100K 5% 1/10W R267 1-216-073-00 METAL CHIP 10K 5% 1/10W R268 1-216-049-11 RES,CHIP 1K 5% 1/10W R271 1-208-449-41 RES,CHIP 3.3K 2% 1/10W R281 1-216-033-00 METAL CHIP 220 5% 1/10W R284 1-216-033-00 METAL CHIP 220 5% 1/10W R285 1-216-033-00 METAL CHIP 220 5% 1/10W R286 1-216-081-00 METAL CHIP 22K 5% 1/10W R287 1-216-081-00 METAL CHIP 22K 5% 1/10W R288 1-216-033-00 METAL CHIP 220 5% 1/10W R291 1-216-085-00 METAL CHIP 33K 5% 1/10W R292 1-216-085-00 METAL CHIP 33K 5% 1/10W R301 1-216-057-00 METAL CHIP 2.2K 5% 1/10W R302 1-208-449-41 RES,CHIP 3.3K 2% 1/10W R303 1-216-113-00 METAL CHIP 470K 5% 1/10W R304 1-208-812-11 RES,CHIP 18K 2% 1/10W R305 1-216-061-00 METAL CHIP 3.3K 5% 1/10W R320 1-216-150-00 RES,CHIP 10 5% 1/8W R321 1-216-049-11 RES,CHIP 1K 5% 1/10W R322 1-216-150-00 RES,CHIP 10 5% 1/8W R323 1-216-150-00 RES,CHIP 10 5% 1/8W R324 1-216-150-00 RES,CHIP 10 5% 1/8W R325 1-216-150-00 RES,CHIP 10 5% 1/8W R326 1-216-065-00 RES,CHIP 4.7K 5% 1/10W R327 1-216-073-00 METAL CHIP 10K 5% 1/10W R351 1-216-070-00 METAL CHIP 7.5K 5% 1/10W R352 1-216-077-00 METAL CHIP 15K 5% 1/10W R353 1-216-089-00 RES,CHIP 47K 5% 1/10W R354 1-216-089-00 RES,CHIP 47K 5% 1/10W R355 1-216-089-00 RES,CHIP 47K 5% 1/10W R356 1-216-089-00 RES,CHIP 47K 5% 1/10W R501 1-216-049-11 RES,CHIP 1K 5% 1/10W R502 1-216-049-11 RES,CHIP 1K 5% 1/10W R503 1-216-049-11 RES,CHIP 1K 5% 1/10W R504 1-216-037-00 METAL CHIP 330 5% 1/10W R505 1-216-049-11 RES,CHIP 1K 5% 1/10W R506 1-216-049-11 RES,CHIP 1K 5% 1/10W R507 1-216-049-11 RES,CHIP 1K 5% 1/10W R508 1-216-097-00 RES,CHIP 100K 5% 1/10W R509 1-216-025-00 RES,CHIP 100 5% 1/10W R510 1-216-025-00 RES,CHIP 100 5% 1/10W R511 1-216-025-00 RES,CHIP 100 5% 1/10W R512 1-216-025-00 RES,CHIP 100 5% 1/10W R515 1-216-089-00 RES,CHIP 47K 5% 1/10W R516 1-216-097-00 RES,CHIP 100K 5% 1/10W R517 1-216-097-00 RES,CHIP 100K 5% 1/10W R518 1-216-687-11 METAL CHIP 33K 0.5% 1/10W R519 1-216-295-00 SHORT 0 (AEP,UK) R520 1-216-097-00 RES,CHIP 100K 5% 1/10W (G) R521 1-216-295-00 SHORT 0 R525 1-216-105-00 RES,CHIP 220K 5% 1/10W R526 1-216-295-00 SHORT 0 R527 1-216-089-00 RES,CHIP 47K 5% 1/10W R528 1-216-057-00 METAL CHIP 2.2K 5% 1/10W R529 1-216-057-00 METAL CHIP 2.2K 5% 1/10W R530 1-216-057-00 METAL CHIP 2.2K 5% 1/10W R531 1-216-057-00 METAL CHIP 2.2K 5% 1/10W R532 1-216-057-00 METAL CHIP 2.2K 5% 1/10W R533 1-216-057-00 METAL CHIP 2.2K 5% 1/10W R534 1-216-295-00 SHORT 0 R535 1-216-295-00 SHORT 0 R536 1-216-295-00 SHORT 0 R537 1-216-295-00 SHORT 0 R538 1-216-097-00 RES,CHIP 100K 5% 1/10W R539 1-216-049-11 RES,CHIP 1K 5% 1/10W R541 1-216-295-00 SHORT 0 R542 1-216-097-00 RES,CHIP 100K 5% 1/10W R543 1-216-105-00 RES,CHIP 220K 5% 1/10W R544 1-216-089-00 RES,CHIP 47K 5% 1/10W R545 1-216-097-00 RES,CHIP 100K 5% 1/10W R546 1-216-097-00 RES,CHIP 100K 5% 1/10W R547 1-216-097-00 RES,CHIP 100K 5% 1/10W R548 1-216-097-00 RES,CHIP 100K 5% 1/10W R549 1-216-097-00 RES,CHIP 100K 5% 1/10W R550 1-216-097-00 RES,CHIP 100K 5% 1/10W R551 1-216-295-00 SHORT 0 R552 1-216-295-00 SHORT 0 R553 1-216-025-00 RES,CHIP 100 5% 1/10W R554 1-216-025-00 RES,CHIP 100 5% 1/10W R556 1-216-097-00 RES,CHIP 100K 5% 1/10W R558 1-216-049-11 RES,CHIP 1K 5% 1/10W R559 1-216-049-11 RES,CHIP 1K 5% 1/10W R561 1-216-089-00 RES,CHIP 47K 5% 1/10W R562 1-216-097-00 RES,CHIP 100K 5% 1/10W R563 1-216-097-00 RES,CHIP 100K 5% 1/10W R564 1-216-675-11 METAL CHIP 10K 0.5% 1/10W R565 1-216-675-11 METAL CHIP 10K 0.5% 1/10W R566 1-216-025-00 RES,CHIP 100 5% 1/10W R567 1-216-025-00 RES,CHIP 100 5% 1/10W R581 1-216-025-00 RES,CHIP 100 5% 1/10W R582 1-216-025-00 RES,CHIP 100 5% 1/10W www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 88 – Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark MAIN SERVO R583 1-216-675-11 METAL CHIP 10K 0.5% 1/10W R584 1-216-675-11 METAL CHIP 10K 0.5% 1/10W R591 1-216-073-00 METAL CHIP 10K 5% 1/10W R901 1-216-025-00 RES,CHIP 100 5% 1/10W R902 1-216-206-00 RES,CHIP 2.2K 5% 1/8W R903 1-216-085-00 METAL CHIP 33K 5% 1/10W R904 1-216-073-00 METAL CHIP 10K 5% 1/10W R905 1-216-073-00 METAL CHIP 10K 5% 1/10W R911 1-216-089-00 RES,CHIP 47K 5% 1/10W R912 1-216-089-00 RES,CHIP 47K 5% 1/10W R913 1-216-085-00 METAL CHIP 33K 5% 1/10W R921 1-216-041-00 METAL CHIP 470 5% 1/10W R922 1-216-081-00 METAL CHIP 22K 5% 1/10W R923 1-216-049-11 RES,CHIP 1K 5% 1/10W R924 1-216-089-00 RES,CHIP 47K 5% 1/10W R925 1-216-075-00 METAL CHIP 12K 5% 1/10W R926 1-216-017-00 RES,CHIP 47 5% 1/10W R927 1-216-025-00 RES,CHIP 100 5% 1/10W R928 1-216-295-00 SHORT 0 R941 1-216-295-00 SHORT 0 R951 1-208-462-41 RES,CHIP 10K 2% 1/10W R952 1-216-025-00 RES,CHIP 100 5% 1/10W R953 1-216-025-00 RES,CHIP 100 5% 1/10W R954 1-216-089-00 RES,CHIP 47K 5% 1/10W R955 1-216-073-00 METAL CHIP 10K 5% 1/10W R956 1-216-224-00 RES,CHIP 12K 5% 1/8W R958 1-216-295-00 SHORT 0 R959 1-216-150-00 RES,CHIP 10 5% 1/8W R971 1-216-206-00 RES,CHIP 2.2K 5% 1/8W R972 1-216-075-00 METAL CHIP 12K 5% 1/10W R973 1-216-081-00 METAL CHIP 22K 5% 1/10W R974 1-216-081-00 METAL CHIP 22K 5% 1/10W < VARIABLE RESISTOR > RV31 1-238-605-31 RES, ADJ, CARBON 470K RV101 1-238-600-11 RES, ADJ, CARBON 10K RV201 1-238-600-11 RES, ADJ, CARBON 10K < SWITCH > S501 1-571-478-11 SWITCH, SLIDE (POWER SELECT) < TUNER > TU1 A-3282-029-A TUNER UNIT (TUX-006/2(E)) < VIBRATOR > X51 1-567-848-11 VIBRATOR, CRYSTAL (7.2MHz) X81 1-760-556-31 VIBRATOR, CRYSTAL (4.332MHz) X501 1-567-098-41 VIBRATOR, CRYSTAL (32.768kHz) X502 1-767-833-21 VIBRATOR, CERAMIC (3.68MHz) ************************************************************* * A-3309-227-A SERVO BOARD, COMPLETE ********************** < CAPACITOR > C1 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V C2 1-164-232-11 CERAMIC CHIP 0.01uF 50V C3 1-135-145-11 TANTALUM CHIP 0.47uF 10% 35V C4 1-163-251-11 CERAMIC CHIP 100PF 5% 50V C5 1-164-182-11 CERAMIC CHIP 0.0033uF 10% 50V C6 1-163-011-11 CERAMIC CHIP 0.0015uF 10% 50V C7 1-163-809-11 CERAMIC CHIP 0.047uF 10% 25V C9 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V C10 1-126-206-11 ELECT CHIP 100uF 20% 6.3V C11 1-135-259-11 TANTAL. CHIP 10uF 20% 6.3V C12 1-163-227-11 CERAMIC CHIP 10PF 0.5PF 50V C13 1-164-232-11 CERAMIC CHIP 0.01uF 50V C14 1-163-989-11 CERAMIC CHIP 0.033uF 10% 25V C15 1-164-232-11 CERAMIC CHIP 0.01uF 50V C16 1-163-989-11 CERAMIC CHIP 0.033uF 10% 25V C17 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V C18 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V C19 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V C20 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V C21 1-163-809-11 CERAMIC CHIP 0.047uF 10% 25V C22 1-163-251-11 CERAMIC CHIP 100PF 5% 50V C23 1-135-259-11 TANTAL. CHIP 10uF 20% 6.3V C24 1-163-259-11 CERAMIC CHIP 220PF 5% 50V C25 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V C26 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V C27 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V C28 1-163-023-00 CERAMIC CHIP 0.015uF 5% 50V C29 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V C30 1-126-603-11 ELECT CHIP 4.7uF 20% 35V C31 1-164-232-11 CERAMIC CHIP 0.01uF 50V C32 1-163-023-00 CERAMIC CHIP 0.015uF 5% 50V C33 1-124-779-00 ELECT CHIP 10uF 20% 16V C34 1-109-982-11 CERAMIC CHIP 1uF 10% 10V C35 1-164-232-11 CERAMIC CHIP 0.01uF 50V C36 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V C37 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V C38 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V C39 1-126-204-11 ELECT CHIP 47uF 20% 16V C40 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V < CONNECTOR > CN1 1-764-616-12 HOUSING, CONNECTOR (PC BOARD) 30P CN2 1-565-728-11 CONNECTOR, FPC 17P CN3 1-770-347-21 CONNECTOR, FPC 6P < IC > IC1 8-752-372-94 IC CXD2507AQ IC2 8-752-074-34 IC CXA1782BQ IC3 8-759-354-16 IC BA6796FP-T1 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 89 – Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark SERVO < JUMPER RESISTOR > JR1 1-216-296-00 SHORT 0 JR2 1-216-296-00 SHORT 0 JR3 1-216-296-00 SHORT 0 JR4 1-216-296-00 SHORT 0 JR5 1-216-296-00 SHORT 0 JR6 1-216-296-00 SHORT 0 JR7 1-216-296-00 SHORT 0 JR8 1-216-296-00 SHORT 0 JR9 1-216-296-00 SHORT 0 JR10 1-216-296-00 SHORT 0 JR11 1-216-296-00 SHORT 0 JR12 1-216-296-00 SHORT 0 JR13 1-216-296-00 SHORT 0 JR14 1-216-296-00 SHORT 0 JR15 1-216-296-00 SHORT 0 JR16 1-216-296-00 SHORT 0 JR17 1-216-296-00 SHORT 0 JR18 1-216-296-00 SHORT 0 JR19 1-216-296-00 SHORT 0 JR20 1-216-296-00 SHORT 0 JR21 1-216-296-00 SHORT 0 JR22 1-216-296-00 SHORT 0 JR23 1-216-296-00 SHORT 0 JR24 1-216-296-00 SHORT 0 JR25 1-216-296-00 SHORT 0 JR26 1-216-296-00 SHORT 0 JR27 1-216-296-00 SHORT 0 JR28 1-216-296-00 SHORT 0 JR29 1-216-296-00 SHORT 0 JR30 1-216-296-00 SHORT 0 JR31 1-216-296-00 SHORT 0 JR32 1-216-296-00 SHORT 0 JR33 1-216-296-00 SHORT 0 JR34 1-216-296-00 SHORT 0 JR35 1-216-296-00 SHORT 0 JR36 1-216-296-00 SHORT 0 JR37 1-216-296-00 SHORT 0 JR38 1-216-296-00 SHORT 0 JR39 1-216-296-00 SHORT 0 JR40 1-216-296-00 SHORT 0 JR41 1-216-296-00 SHORT 0 JR43 1-216-296-00 SHORT 0 JR44 1-216-296-00 SHORT 0 JR45 1-216-296-00 SHORT 0 JR46 1-216-296-00 SHORT 0 < COIL > L1 1-412-058-11 INDUCTOR CHIP 10uH L2 1-412-058-11 INDUCTOR CHIP 10uH L3 1-412-058-11 INDUCTOR CHIP 10uH < TRANSISTOR > Q1 8-729-904-60 TRANSISTOR DTB113ZK Q2 8-729-904-86 TRANSISTOR 2SB1197K-Q < RESISTOR > R1 1-216-073-00 METAL CHIP 10K 5% 1/10W R2 1-216-097-00 RES,CHIP 100K 5% 1/10W R3 1-216-121-00 RES,CHIP 1M 5% 1/10W R4 1-216-061-00 METAL CHIP 3.3K 5% 1/10W R5 1-216-061-00 METAL CHIP 3.3K 5% 1/10W R6 1-216-073-00 METAL CHIP 10K 5% 1/10W R7 1-216-009-00 METAL CHIP 22 5% 1/10W R8 1-216-119-00 METAL CHIP 820K 5% 1/10W R9 1-216-119-00 METAL CHIP 820K 5% 1/10W R10 1-216-073-00 METAL CHIP 10K 5% 1/10W R11 1-216-073-00 METAL CHIP 10K 5% 1/10W R14 1-216-085-00 METAL CHIP 33K 5% 1/10W R15 1-216-085-00 METAL CHIP 33K 5% 1/10W R16 1-216-077-00 METAL CHIP 15K 5% 1/10W R17 1-216-081-00 METAL CHIP 22K 5% 1/10W R19 1-216-079-00 METAL CHIP 18K 5% 1/10W R20 1-216-105-00 RES,CHIP 220K 5% 1/10W R21 1-216-105-00 RES,CHIP 220K 5% 1/10W R22 1-216-085-00 METAL CHIP 33K 5% 1/10W R23 1-216-121-00 RES,CHIP 1M 5% 1/10W R24 1-216-073-00 METAL CHIP 10K 5% 1/10W R27 1-216-295-00 SHORT 0 R28 1-216-101-00 METAL CHIP 150K 5% 1/10W R29 1-216-097-00 RES,CHIP 100K 5% 1/10W R30 1-216-097-00 RES,CHIP 100K 5% 1/10W R31 1-216-081-00 METAL CHIP 22K 5% 1/10W R32 1-216-109-00 METAL CHIP 330K 5% 1/10W R33 1-216-105-00 RES,CHIP 220K 5% 1/10W R34 1-216-009-00 METAL CHIP 22 5% 1/10W R35 1-216-065-00 RES,CHIP 4.7K 5% 1/10W R36 1-216-097-00 RES,CHIP 100K 5% 1/10W R37 1-216-117-00 METAL CHIP 680K 5% 1/10W R38 1-216-109-00 METAL CHIP 330K 5% 1/10W R39 1-216-101-00 METAL CHIP 150K 5% 1/10W R40 1-216-114-00 RES,CHIP 510K 5% 1/10W R41 1-216-093-00 METAL CHIP 68K 5% 1/10W R42 1-216-103-00 METAL CHIP 180K 5% 1/10W R43 1-216-097-00 RES,CHIP 100K 5% 1/10W R44 1-216-085-00 METAL CHIP 33K 5% 1/10W R45 1-216-081-00 METAL CHIP 22K 5% 1/10W R46 1-216-097-00 RES,CHIP 100K 5% 1/10W R47 1-216-105-00 RES,CHIP 220K 5% 1/10W R48 1-216-073-00 METAL CHIP 10K 5% 1/10W R49 1-216-065-00 RES,CHIP 4.7K 5% 1/10W R50 1-216-065-00 RES,CHIP 4.7K 5% 1/10W R51 1-216-295-00 SHORT 0 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 90 – Sony Corporation Personal & Mobile Communication Company Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark WX-C570R 98E047542-1 Printed in Hungary C1998. 5 Published by Quality Assurance Dept. 9-925-954-11 The components identified by mark ! or dotted line with mark. ! are critical for safety. Replace only with part number specified. SUB SERVO < VARIABLE RESISTOR > RV1 1-238-091-11 RES, ADJ, CERMET 22K RV4 1-238-091-11 RES, ADJ, CERMET 22K ************************************************************* * 1-659-834-11 SUB BOARD ********** < CONNECTOR > CN1 1-770-347-21 CONNECTOR, FPC 6P ************************************************************* SW BOARD (SUPPLIED WITH MAIN BOARD, COMPLETE) ********** < DIODE > D1000 8-719-404-49 DIODE MA111 < TRANSISTOR > Q1001 8-729-424-18 TRANSISTOR UN2113 < RESISTOR > R1000 1-216-295-00 SHORT 0 ************************************************************* MISCELLANEOUS *************** 2 1-776-527-71 CORD (WITH CONNECTOR) (ISO) (POWER) 257 1-659-880-11 MOTOR FLEXIBLE BOARD !260 8-820-010-06 PICK-UP, OPTICAL KSS-521A/K1RP 262 1-659-881-11 PICK-UP FLEXIBLE BOARD F901 1-532-877-11 FUSE (BLADE TYPE) (AUTO FUSE) 10A HP901 1-500-157-21 HEAD, MAGNETIC (PLAYBACK) M901 X-3371-664-2 MOTOR ASSY (SPINDLE) M902 A-3291-674-A MOTOR ASSY, SLED M903 A-3291-676-A MOTOR SUB ASSY, LOADING M904 A-3291-665-A MOTOR ASSY, MAIN (CAPSTAN/REEL) ************************************************************* ACCESSORIES & PACKING MATERIALS ******************************** 3-862-805-11 MANUAL, INSTRUCTION (ENGLISH,SPANISH, PORTUGUESE,SWEDISH) 3-862-806-11 MANUAL, INSTRUCTION, INSTALL (ENGLISH, SPANISH,PORTUGUESE,SWEDISH) X-3374-605-2 COVER ASSY, FRONT ************************************************************* ************** HARDWARE LIST ************** #1 7-685-792-09 SCREW +PTT 2.6X6 (S) #2 7-685-794-09 SCREW +PTT 2.6X10 (S) #3 7-685-105-19 TPG +P 2X8, TYPE 2, NON-SLIT #4 7-685-796-09 SCREW +PTT 2.6X14 (S) #5 7-627-850-28 SCREW, PRECISION +P 1.4X3 #6 7-627-000-00 SCREW, PRECISION +P 1.7X2.2 TYPE 3 #7 7-628-253-00 SCREW +PS 2X4 #8 7-627-553-37 SCREW, PRECISION +P 2X3 TYPE 3 #9 7-627-553-17 SCREW, PRECISION +P 2X2 TYPE 3 #10 7-624-104-04 STOP RING 2.0, TYPE -E ************************************************************* PARTS FOR INSTALLATION AND CONNECTIONS *************************************** 351 X-3375-549-1 SCREW ASSY (6) 352 3-936-590-01 FRAME (N), ORNAMENT 353 1-776-527-71 CORD (WITH CONNECTOR) (ISO) (POWER) 354 1-465-459-21 ADAPTOR, ANTENNA SW www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com
