Ver 1.0 2000.03 RADIO CASSETTE PLAYER SPECIFICATIONS US Model Model Name Using NEW Mechanism Type Similar Mechanism WM-FX277 : MF-WMFX277-114 Tape Transport WM-FX467/FX467ST : MF-WMFX467-114 Photo : WM-FX467 SERVICE MANUAL • Frequency range FM: 87.5 - 108 MHz AM: 530 - 1,710 kHz TV: 2 - 13 ch • Power requirements 3V DC batteries R6 (AA) x 2 • Dimensions (w/h/d) Approx. 91.4 x 115.5 x 35.0 mm (3 5⁄8 x 4 5⁄8 x 1 7⁄16 inches) incl. projecting parts and controls • Mass FX467/FX467ST: Approx. 155 g (5.5 oz)/Approx. 235 g (8.3 oz) incl. batteries and a cassette FX277: Approx. 145 g (5.2 oz)/Approx. 225 g (8.0 oz) incl. batteries and a cassette • Supplied accessories Stereo headphones or Stereo earphones (1) Carrying case with belt clip(1) Design and specifications are subject to change without notice. Battery life (approximate hours) (EIAJ*) Sony alkaline LR6 (SG) Sony R6P (SR) Tape playback 25 7.5 Radio reception 40 14 * Measured value by the standard of EIAJ (Electronic Industries Association of Japan). (Using a Sony HF series cassette tape) Note • The battery life may shorten depending on the operation of the unit. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 2007.04.30 QQ :376315150 手机:13942296513 – 2 – Specifications ........................................................................... 1 1. GENERAL Location and Function of Controls .................................... 2 2. DISASSEMBLY 2-1. Cabinet (Front) ........................................................... 3 2-2. Main Board ................................................................. 3 2-3. Mechanism Deck ........................................................ 4 2-4. Belt, Capstan/Reel Motor (M601) .............................. 4 2-5. Cassette Holder ........................................................... 5 3. ADJUSTMENTS 3-1. Mechanical Adjustments............................................. 6 3-2. Electrical Adjustments ................................................ 6 4. DIAGRAMS 4-1. Explanation of IC Terminals....................................... 9 4-2. Block Diagram.......................................................... 10 4-3. Printed Wiring Boards .............................................. 13 4-4. Schematic Diagram................................................... 17 5. EXPLODED VIEWS 5-1. Cabinet Section ......................................................... 21 5-2. Mechanism Deck Section (WM-FX277).................. 22 5-3. Mechanism Deck Section (WM-FX467/FX467ST) ........................................... 23 6. ELECTRICAL PARTS LIST ................................... 24 Flexible Circuit Board Repairing • Keep the temperature of the soldering iron around 270°C during repairing. • Do not touch the soldering iron on the same conductor of the circuit board (within 3 times). • Be careful not to apply force on the conductor when soldering or unsoldering. Notes on chip component replacement • Never reuse a disconnected chip component. • Notice that the minus side of a tantalum capacitor may be dam- aged by heat. TABLE OF CONTENTS SECTION 1 GENERAL LOCATION AND FUNCTION OF CONTROLS This section is extracted from instruction manual. HOLD OFF AM FM TV TUNING + / - ENTER MEGA BASS NORM • CrO2 / METAL DX • LOCAL AVLS NORM • LIMIT VOLUME x STOP M N PLAY m DIR • Y (FX467 / FX467ST only) MODE • s / d (FX467 / FX467ST only) PRESET + FX467 / FX467ST i www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 3 – SECTION 2 DISASSEMBLY Note : Follow the disassembly procedure in the numerical order given. 2-1. CABINET (FRONT) 2-2. MAIN BOARD z The equipment can be removed using the following procedure. Main board Cabinet (Front) Cassette holder Mechanism deck Belt, Capstan/reel motor (M601) Set Cabinet (Front) Cabinet (center) sub ASSY Cassette holder 4 Claw 4 Claw 2 5 1 Claws 1 Claws 3 Claws 1 Claws Main board 1 Screw Orange Black White Red Cabinet (center) sub ASSY Head flexible board 2 Remove solder 3 Claws 4 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 4 – 2-3. MECHANISM DECK 2-4. BELT, CAPSTAN/REEL MOTOR (M601) Mechanism deck Cabinet (center) sub ASSY 1 Claws 2 2 Belt Stopper 1 Claw 4 Capstan/reel motor (M601) wheel ASSY (P), capstan (FX467/FX467ST) wheel ASSY (P), capstan Belt • How to apply the belt Capstan/reel motor (M601) 3 Screws (M1.4) Mechanism deck www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 5 – Cassette holder 4 Spring (torsion) Hinge Hinge 1 5 Hinge Cabinet (center) sub ASSY Hinge Projection Projection 3 Move the hinge away from projection 2 Move the hinge away from projection Spring (torsion) Hinge Hinge Cassette holder Cabinet (center) sub ASSY 1 2 4 3 1 Insert the spring (torsion) to the L shape slot as shown in the figure. 2,3 Insert the hinge of the “Cassette holder ”. 4 Close the “Cassette holder” then press it. 2-5. CASSETTE HOLDER z CAUTIONS DURING ASSEMBLY www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 6 – SECTION 3 ADJUSTMENTS 3-2. ELECTRICAL ADJUSTMENTS PRECAUTION • Supplied voltage : 2.5V. • Switch and control position MEGA BASS : OFF VOLUME control : maximum AVLS : NORM TAPE SECTION Test Tape Type Signal Used for WS-48A 3kHz, 0dB Tape Speed Adjustment Tape Speed Adjustment Procedure : (FX277) 1. Playback WS-48A (tape center part) and adjust RV601 so that the frequency counter reading becomes 3,000Hz. Standard value : 2,985–3,015Hz 2. Playback WS-48A (tape top and end) . Check that frequency counter reading is within ±1.0% of the reading of step 1. (FX467/FX467ST) 1. Playback WS-48A (tape center part) in the FWD state and ad- just RV601 so that the frequency counter reading becomes 3,000Hz. Standard value : 2,985–3,015Hz 2. Playback WS-48A (tape center part) in the REV state. Check that frequency counter reading is within ±1.0% of the reading of step 1. Adjustment Location : 0 dB = 0.775V set test tape WS-48A (3kHz, 0dB) frequency counter 32 Ω phones jack (J301) 3-1. MECHANICAL ADJUSTMENTS PRECAUTION 1. Clean the following parts with a denatured-alcohol-moistened swab : playback head pinch roller capstan rubber belt 2. Demagnetize the playback head with a head demagnetizer. Do not use a magnetized screwdriver for the adjustments. 3. These measurement and adjustment should be performed with the rated power supply voltage (2.5 V) unless otherwise noted. Torque Measurement Mode Torque meter Meter reading FWD 20 – 42 g • cm CQ-102C (0.28 – 0.58 oz• inch) FWD less than 2 g • cm back tension (less than 0.027 oz• inch) REV 20 – 42 g • cm (FX467/FX467ST) (0.28 – 0.58 oz• inch) REV CQ-102RC less than 2 g • cm back tension (less than 0.027 oz• inch) (FX467/FX467ST) FF, REW CQ-201B more than 60 g • cm (more than 0.84 oz• inch) RV601 : Tape speed Adjustment www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 7 – TUNER SECTION AM Section BAND : AM TV/FM Section BAND : TV or FM AM IF ADJUSTMENT Adjust for a maximum reading on level meter. RV2 450kHz AM FREQUENCY COVERAGE ADJUSTMENT Adjust parts Frequency display Reading on digtal voltmeter Confirmation 530kHz Standard value : 3V or less L7 1,710kHz Adjustment value : 10.0V Standard value : 9.9-10.1V AM TRACKING ADJUSTMENT Adjust for a maximum reading on level meter. L3 620kHz CT1 1,400kHz TV and FM FREQUENCY COVERAGE CONFIRMATION Frequency display Reading on digtal voltmeter Confirmation 2CH (TV) Standard value : 1.6 - 2.2V Confirmation 108MHz (FM) Standard value : 11.0V or less FM TRACKING ADJUSTMENT Adjust for a maximum reading on level meter. L4 98MHz Confirmation 108MHz TV TRACKING ADJUSTMENT Adjust for a maximum reading on level meter. L5 2CH Confirmation 13CH Adjustment Location : Main board (See page 8) 0 dB = 1µV • Repeat the procedures in each adjustment several times, and the frequency coverage and tracking adjustments should be finally done by the trimmer capacitors. AM RF signal generator 30% amplitude modulation by 400Hz signal. Output level : as low as possible Put the lead-wire antenna close to the set. set 32 Ω phones jack (J301) level meter R205 R105 C1 C35 C310 C312 C39 C40 L4 L5 TUNER GND TP (FM/TV IN) (L) STID S304 S303 -2 -1 -2 -1 FM RF signal generator 22.5kHz frequency deviation by 400Hz signal. Output level : as low as possible TP (FM/TV IN) 0.01µF [MAIN BOARD] (Side B) Frequency Coverage Adjustment Setting : D401 D402 C401 C403 C405 C406 R401 R402 R403 R19 C402 C404 T401 GND TP (VT) TP (VT) TP (GND) [MAIN BOARD] (Side B) digital voltmeter (DC range) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 8 – Adjustment Location : IC1 [MAIN BOARD] (SIDE A) RV1 : FM VCO Adjustment L7 : AM Frequency Coverage Adjustment RV2 : AM IF Adjustment L4 : FM Tracking Adjustment L5 : TV Tracking Adjustment L3 : AM Tracking Adjustment CT1 : AM Tracking Adjustment FM VCO Adjustment Procedure : C1 C35 C310 C312 C39 C40 L4 L5 TP (FM/TV IN) (L) STID S304 S303 -2 -1 FM RF signal generator Carrier frequency : 98MHz Modulation : No modulation Output level : 0.1V (100dB/ µV) TP (FM/TV IN) 0.01µF [MAIN BOARD] (Side B) 1. Connect the frequency counter as shown in the figure. 2. Turn the set to 98MHz. 3. Adjust RV1 for 76kHz reading frequency counter. Standar value : 75.8 - 76.2kHz 3 C25 R4 R6 RV1 L1 L2 C4 C5 C6 C8 C11 C15 C10 8 C19 R9 R15 D2 D4 C20 C21 C26 C28 C31 C34 IC1 R17 L6 37 C3 R20 40 31 35 30 21 25 20 11 15 1 5 10 frequency counter 33K Ω 1 F IC1 7 pin IC1 0 pin + µ [MAIN BOARD] (Side A) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 9 – – 10 – – 12 – – 11 – 4-2. BLOCK DIAGRAM • Signal path. F : FM, TV f : AM E : PB WM-FX277/FX467/FX467ST Pin No. Pin name I/O Descliption 1 XOUT O Crystal oscillator output (75kHz). 2 TEST2 – Not used (Ground). 3 PA3 I Key input. 4 PA2 I Key input. 5 PA1 I Key input. 6 PA0 I Key input. 7 PB3 O Key output. 8 PB2 O Key output. 9 PB1 O Key output. 10 LOCAL/DX – Not used (OPEN). 11 HOLD I HOLD switch input. “H”: ON, “L”: OFF 12 LOCAL SW – Not used (OPEN). 13 TV (H) – Not used (OPEN). 14 BAND O Band select signal output. 15 SD I Tuning signal detect input. 16 COMP I Comparator input. 17 N/R SW I N/R switch input. 18 BACK UP I Back up voltage input. 19 AMP ON O Power ON/OFF signal output. 20 BEEP O Beep signal output. 21 BATT CHECK I Back up cancel input. 22 BATT REF I A/D reference voltage input. 23 –––––––––– – Not used (Ground). 24 VSS – Ground terminal. 25 RADIO ON O Radio ON signal output. 26 MEGA BASS O MEGA BASS ON signal output. 27 MUTE O Mute ON signal output. 28 TAPE I Tape ON input. 29 PRE CTL O Preamplifier control output. 30 MOTOR CTL O Motor control output. 31 ID I Destination select input. 32-44 S1-13 O LCD segment output. 45-48 COM1-4 O LCD common output. 49-52 DBR1-4 – LCD power supply. 53 RESET I Reset input (Fixed “H”). 54 TU VCC – Not used (OPEN). 55 VDD – Power supply. 56 FM IN I FM input. 57 AM IN I AM input. 58 VSS – Ground terminal. 59 E.O O Error output. 60 LPF IN I LPF input. 61 LPF OUT O LPF output. 62 LPF GND – Ground terminal. 63 TEST 1 – Not used (Ground). 64 X IN I Crystal oscillator input (75kHz). SECTION 4 DIAGRAMS 4-1. EXPLANATION OF IC TERMINALS IC702 LC72348W-CFX1705 SYSTEM CONTROL w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com S701 HOLD ON OFF PRESET + S710 TV S711 FM S712 AM OFF S708 ENTER MEGABASS FB101 FB201 FB301 R18 R205 R105 R11 C107 C207 C24 C29 D703 D401 D402 Q401 C401 C403 C405 C406 R401 R403 R19 C35 C311 C310 C39 R107 R207 C402 C40 JR1 JR2 C712 L4 RV301 L7 RV601 (TAPE SPEED) C16 C9 C12 C17 C404 C303 C308 C305 C502 C104 C204 L5 T401 PB3 (R) PW GND (L) MEGA MIX IN MIX IN GND +B TAPE +B PRE GND VREF PA1 BASS PB1 TUNE COMP PRE CTL TUNER GND (R) PA2 PWIN (L) MIX OUT TP (FM/TV IN) PWIN (R) VREF (L) MIX OUT PWOUT PWOUT (R) (L) STID (COM) PWOUT GND GND PA3 TUNER VCC AMP ON PA0 PB2 VDD MUTE VCC +B L-CH R-CH D1 L-CH R-CH HP601 PLAYBACK HEAD BCE AVLS S304 S304 S303 S303 -2 -1 -2 -1 -2 -1 CrO2/METAL NORM LIMIT NORM L3 AM FERRITE-ROD ANTENNA ND701 LIQUID CRYSTAL DISPLAY PANEL ORG BLK WHT RED W V U COM M M601 CAPSTAN/REEL MOTOR 11 (11) FX277 : 1-677-908- FX467/467ST : 1-677-907- FX277 : 1-677-908- FX467/467ST : 1-677-907- DRY BATTERY SIZE "AA" (IEC DESIGNATION R6) 2PCS, 3V [MAIN BOARD] (SIDE B) PRE GND L-CH R-CH C30 PRESET – LOCAL DX 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 A 1 B C D E F G H L-CH R-CH R-CH L-CH FWD REV HP601 PLAYBACK HEAD [HEAD FLEXIBLE BOARD] [HEAD FLEXIBLE BOARD] FX277 FX467/FX467ST 02 ECB Q701 R702 R501 Q502 R504 R503 R502 Q501 C501 C702 C704 C705 C707 C708 C709 C710 C711 R718 R720 R717 L702 R605 R606 R607 R304 R710 R106 R206 C703 1 5 10 16 17 20 25 30 32 33 35 40 45 48 49 50 55 60 64 R711 R712 R713 R714 R715 R716 IC701 C701 R704 R705 R706 R707 C309 R303 C106 C206 R701 R708 C603 R201 R202 R203 R101 R102 R103 R104 R601 R603 C101 C201 C302 C304 C105 C205 Q301 R305 C604 C605 C606 C607 R604 C306 C108 C208 CT1 C22 C301 R301 R10 R13 R14 R16 D3 Q3 C27 C25 C32 C33 R3 R4 R5 R6 R7 RV1 RV2 L1 L2 C4 C5 C6 C7 C8 C11 C13 C14 C15 C10 C18 C19 R8 R9 R15 D2 D4 C20 C21 C23 C26 C28 C31 C34 TH601 X701 IC702 IC301 IC1 L401 R17 R302 C307 R204 FB302 R722 C714 R703 R12 L6 C3 R721 C203 C103 C602 C601 R602 S301 (TAPE ON) R20 C715 2 1 3 37 40 45 36 48 1 5 10 13 15 20 12 1 5 1012 25 30 35 24 40 31 35 30 21 25 20 11 15 1 5 10 [MAIN BOARD] (SIDE A) 11 (11) FX277 FX467/FX467ST R202 R203 R101 R103 R104 R601 C101 C102 C201 C202 R204 C203 C103 J301 i RV301 VOLUME w S709 S705 TUNING– S702 TUNING+ TP (VT) S703 S706 S704 C503 B EC B EC S302 (N/R SW) FX467/FX467ST – 15 – – 16 – – 13 – – 14 – WM-FX277/FX467/FX467ST D1 F-2 D2 C-18 D3 D-18 D4 D-18 D401 B-6 D402 B-5 D703 B-10 IC1 C-18 IC301 E-14 IC701 E-15 IC702 D-15 Q3 D-18 Q301 F-14 Q401 B-5 Q501 C-13 Q502 B-13 Q701 B-13 Ref. No. Location z Semiconductor Location 4-3. PRINTED WIRING BOARDS Note: • X : parts extracted from the component side. • a : Through hole. • f : internal component. • b : Pattern of the rear side. w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 17 – – 19 – – 18 – WM-FX277/FX467/FX467ST 4-4. SCHEMATIC DIAGRAM Note: • All capacitors are in µF unless otherwise noted. pF: µµF 50 WV or less are not indicated except for electrolytics and tantalums. • All resistors are in Ω and 1/4 W or less unless otherwise specified. • f : internal component. • U : B+ Line. • H : adjustment for repair. • Power voltage is dc 3V and fed with regulated dc power supply from battery terminal. • Voltages and waveforms are dc with respect to ground under no-signal (detuned) conditions. no mark : FM ( ) : AM (RADIO SECTION), PLAY (TAPE SECTION) < > : TV • Voltages are taken with a VOM (Input impedance 10 MΩ). Voltage variations may be noted due to normal produc- tion tolerances. • Waveforms are taken with a oscilloscope. Voltage variations may be noted due to normal produc- tion tolerances. • Circled numbers refer to waveforms. • Signal path. F : FM, TV E : PB r Waveforms 1 IC702 1 XOUT 2 3 VOLT/DIV : 0.1 V AC TIME/DIV : 5 µsec Q401 C Q401 B VOLT/DIV : 0.5 V AC TIME/DIV : 0.1 µsec VOLT/DIV : 10mV AC TIME/DIV : 0.1 µsec 425 mVp-p 75 kHz 1.8 Vp-p 319 nsec 55 mVp-p 319 nsec z Refer to page 20 for IC Block Diagrams. w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 61 X-3376-169-1 CLUTCH ASSY 62 3-920-990-01 SPRING (UD), COMPRESSION 63 3-921-335-01 WASHER, LEVER 64 3-923-530-01 SLEEVE (M) 65 3-728-091-01 WASHER, STOPPER 66 3-938-613-01 LEVER (OW), DETECTION (FX277) 67 3-703-816-31 SCREW (M1.4), SPECIAL HEAD 68 3-016-989-01 SPRING (SW-CP) 69 X-3376-206-1 CHASSIS COMP ASSY (GL-02) (FX277) HP601 1-500-641-11 HEAD, MAGNETIC (PLAYBACK) (FX277) M601 1-763-073-11 MOTOR(CAPSTAN/REEL) (INCLUDING PULLY) – 20 – – 22 – – 21 – z IC Block Diagrams. IC301 LB8115W-NA-TLM 1 2 36 35 34 33 32 31 30 29 28 27 26 25 13 14 15 16 17 18 19 20 21 22 23 24 48 47 46 45 44 43 42 41 40 39 38 37 COM RI VREF POWER OUT (COM) POWER OUT (R) VCC POWER MUTE POWER IN (L) POWER IN (R) MIX OUT (L) MIX OUT (R) LP.2 HP IN (R) HP IN (L) DET OUT MVREF IN+ VSP MIX IN (R) MIX IN (L) LOW BOOST SW M-GND R.VREF SYSTEM POWER OUT (L) POWER GND MVCC DR WOUT MP-GND VOUT UOUT FC OUT OSC UB VB WB 3 4 5 6 7 8 9 10 11 12 PRE NF (L) PRE OUT (R) PRE NF (R) FWD IN (R) REV IN (R) REV IN (L) FWD IN (L) S/S PRE GND PRE OUT (L) BIAS R.F REF SYS CONT DET VREF SPEED LOW BOOST PRE DRIVER OPERATION LOGIC OSC PLUSE DET REF VOLTAGE REF VOLTAGE FOR SPEED CONTROL CURRENT DET OPERATION DET FWD/ REV FREQ CARC. + – IC1 CXA1960Q + – 12 13 14 19 15 TVIN MREF GND FMIB IFCT NC FMIN FMRO OLAG ARFI REGV TVRO FTLO BAND TUNE PLLO FALC COMP 37 38 39 40 AAGC DETO PLT2 MPXI MPRM V12M MUTE PLT1 PLL1 PLL2 MPX DECODER AM BPF PSN 1/X FM/TV LPF PD VCO 1/2 1/2 STID 14V PLAP TUNE 38kHz STEREO AUDIO R STEREO AUDIO L 19kHz 1.65V 1.25V 36 8 9 10 VCO STID MCNT GND VCC 1 4 2 3 5 6 MPRG LOUT ROUT DDCN PLLI 7 + – + – 35 34 FM DET 150kHz FM LMT OL DET TV RF AMP FM RF AMP AM RF AMP 45kHz 31 32 33 MUTE AGC AMP AM AGC 1.25V AM/FM: 1/2 TV: 1/8 1.25V 18 17 16 FMBF AMLO AM OSC FM/TV OSC 20 30 29 27 28 23 24 25 26 22 21 11 SECTION 5 EXPLODED VIEWS NOTE : • -XX, -X mean standardized parts, so they may have some difference from the original one. • Color indication of Appearance Parts Example : KNOB, BALANCE (WHITE) ••• (RED) ↑ ↑ Parts color Cabinet's color • Items marked “ * ”are not stocked since they are seldom required for routine service. Some delay should be anticipated when ordering these items. • The mechanical parts with no reference number in the exploded views are not supplied. • Hardware (# mark) list and accessories and packing materials are given in the last of this parts list. Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 5-1. CABINET SECTION 1 3-044-867-01 CABINET (FRONT) (FX467,FX467ST) 1 3-044-867-11 CABINET (FRONT) (FX277) 2 3-044-868-01 WINDOW (LCD) (FX467,FX467ST) 2 3-044-868-11 WINDOW (LCD)(SLIVER) (FX277) 2 3-044-868-21 WINDOW (LCD)(BLUE) (FX277) 3 3-044-869-01 KNOB(HOLD) 4 3-044-870-01 BUTTON (PRESET) 4 3-044-870-11 BUTTON (PRESET) (FX277) 5 3-015-285-01 SCREW(M1.4),TOOTHED LOCK (WH) 6 A-3021-322-A MAINBOARD, COMPLETE (FX467,FX467ST) 6 A-3021-323-A MAINBOARD, COMPLETE (FX277) 7 3-044-865-01 STOPPER 8 3-007-006-21 BUTTON (STOP) 9 3-007-004-21 BUTTON (FF) 10 3-030-054-01 BUTTON (PLAY) 11 3-007-005-21 BUTTON (REW) 12 3-044-864-01 CASSETTE, HOLDER 13 3-007-012-01 SPRING (TORSION) 14 X-3378-641-1 CABINET (CENTER) SUB ASSY (FX467,FX467ST) 14 X-3378-642-1 CABINET (CENTER) SUB ASSY (FX277) 15 3-007-011-01 SPRING (CASSETTE) 17 3-030-055-01 TERMINAL (+), BATTERY 18 3-007-010-01 TERMINAL (-), BATTERY * 19 1-694-218-31 CONNECTOR, RUBBER * 20 3-044-866-01 HOLDER, LCD L3 1-754-124-11 ANTENNA, FERRITE-ROD (AM TRACKING) ND701 1-803-944-11 PANEL, LIQUID CRYSTAL DISPLAY L3 ND701 not supplied 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 17 18 19 20 Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 5-2. MECHANISM DECK SECTION (WM-FX277) (MF-WMFX277-114) HP601 M601 not supplied 51 52 53 54 55 55 56 56 58 59 68 61 62 63 64 65 66 67 57 69 60 not supplied not supplied not supplied not supplied not supplied 51 X-3369-749-1 PINCH LEVER (N) ASSY 52 3-920-996-01 SPRING (PINCH N) 53 X-3372-619-1 WHEEL ASSY (P), CAPSTAN 54 3-703-816-73 SCREW (M1.4), SPECIAL HEAD (FX277) 55 3-921-042-01 GEAR(REEL) 56 3-921-797-01 WASHER 57 3-036-664-11 SPRING (FR LEVER OWN) (FX277) 58 3-013-560-11 BELT (FX277) 59 3-015-436-01 SPRING (STOP) 60 3-013-142-01 SPRING (FR-CP) 51 X-3369-749-1 PINCH LEVER (N) ASSY 52 3-920-996-01 SPRING (PINCH N) 53 X-3372-619-1 WHEEL ASSY (P), CAPSTAN 54 3-703-816-73 SCREW (M1.4), SPECIAL HEAD (FX277) 55 3-921-042-01 GEAR(REEL) 56 3-921-797-01 WASHER 57 3-036-664-11 SPRING (FR LEVER OWN) (FX277) 58 3-013-560-11 BELT (FX277) 59 3-015-436-01 SPRING (STOP) 60 3-013-142-01 SPRING (FR-CP) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 23 – 5-3. MECHANISM DECK SECTION (WM-FX467/FX467ST) (MF-WMFX467-114) HP601 M601 not supplied 101 102 103 103 104 105 105 106 107 106 109 110 125 112 113 114 115 116 117 118 119 120 121 122 123 124 108 126 111 not supplied not supplied not supplied not supplied not supplied Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 101 X-3369-749-1 PINCH LEVER (N) ASSY 102 3-920-996-01 SPRING (PINCH N) 103 X-3372-619-1 WHEEL ASSY (P), CAPSTAN 104 3-704-197-71 SCREW (M1.4) (FX467,FX467ST) 105 3-921-042-01 GEAR(REEL) 106 3-921-797-01 WASHER 107 3-920-993-02 SPRING (NR) (FX467,FX467ST) 108 3-933-324-01 SPRING (FR LEVER) (FX467,FX467ST) 109 3-938-657-01 BELT (FX467,FX467ST) 110 3-015-436-01 SPRING (STOP) 111 3-013-142-01 SPRING (FR-CP) 112 3-921-053-01 LEVER, D SELECTION (FX467,FX467ST) 113 X-3376-169-1 CLUTCH ASSY 114 3-920-990-01 SPRING (UD), COMPRESSION 115 3-921-335-01 WASHER, LEVER 116 3-923-530-01 SLEEVE (M) 117 3-728-091-01 WASHER, STOPPER 118 3-921-052-11 LEVER (A), DETECTION (FX467,FX467ST) 119 3-920-994-11 SPRING (D SELECTION) (FX467,FX467ST) 120 3-929-419-01 LEVER (BR), DETECTION (FX467,FX467ST) 121 3-703-816-31 SCREW (M1.4), SPECIAL HEAD 122 3-921-023-01 LEVER, M SELECTION (FX467,FX467ST) 123 X-3369-748-1 PINCH LEVER (R) ASSY (FX467,FX467ST) 124 3-920-997-01 SPRING (PINCH R) (FX467,FX467ST) 125 3-016-989-01 SPRING (SW-CP) 126 X-3372-960-1 CHASSIS COMP ASSY (GL-L)(FX467,FX467ST) HP601 1-500-648-11 HEAD, MAGNETIC (PLAYBACK) (FX467,FX467ST) M601 1-763-073-11 MOTOR(CAPSTAN/REEL) (INCLUDING PULLY) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 24 – NOTE : • Due to standardization, replacements in the parts list may be different from the parts specified in the diagrams or the components used on the set. • -XX, -X mean standardized parts, so they may have some difference from the original one. • RESISTORS All resistors are in ohms METAL : Metal-film resistor METAL OXIDE :Metal oxide-film resistor F : nonflammable • Items marked “ * ”are not stocked since they are seldom required for routine service. Some delay should be anticipated when ordering these items. • SEMICONDUCTORS In each case, u : µ , for example : uA.... : µ A.... , uPA.... : µ PA.... uPB.... : µ PB.... , uPC.... : µ PC.... uPD.... : µ PD.... • CAPACITORS uF : µ F • COILS uH : µ H When indicating parts by reference num- ber, please include the board. SECTION 6 ELECTRICAL PARTS LIST Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark A-3021-322-A MAIN BOARD, COMPLETE (FX467,FX467ST) A-3021-323-A MAIN BOARD, COMPLETE (FX277) ********************* < CAPACITOR > C3 1-162-927-11 CERAMIC CHIP 100PF 5% 50V C4 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V C5 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V C6 1-115-156-11 CERAMIC CHIP 1uF 10V C7 1-164-315-11 CERAMIC CHIP 470PF 5% 50V C8 1-113-619-11 CERAMIC CHIP 0.47uF 10V C9 1-126-514-11 ELECT 22uF 20% 6.3V C10 1-162-910-11 CERAMIC CHIP 5PF 0.25PF 50V C11 1-115-156-11 CERAMIC CHIP 1uF 10V C12 1-126-794-11 ELECT 4.7uF 20% 25V C13 1-115-156-11 CERAMIC CHIP 1uF 10V C14 1-115-156-11 CERAMIC CHIP 1uF 10V C15 1-162-910-11 CERAMIC CHIP 5PF 0.25PF 50V C16 1-126-794-11 ELECT 4.7uF 20% 25V C17 1-126-791-11 ELECT 10uF 20% 16V C18 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V C19 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V C20 1-115-156-11 CERAMIC CHIP 1uF 10V C21 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C22 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V C23 1-104-847-11 TANTAL. CHIP 22uF 20% 4V C24 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C25 1-162-907-11 CERAMIC CHIP 2PF 0.25PF 50V C26 1-115-416-11 CERAMIC CHIP 1000PF 5% 25V C27 1-115-416-11 CERAMIC CHIP 1000PF 5% 25V C28 1-115-416-11 CERAMIC CHIP 1000PF 5% 25V C29 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V C30 1-126-791-11 ELECT 10uF 20% 16V C31 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C32 1-115-416-11 CERAMIC CHIP 1000PF 5% 25V C33 1-115-416-11 CERAMIC CHIP 1000PF 5% 25V C35 1-163-251-11 CERAMIC CHIP 100PF 5% 50V C39 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C40 1-115-416-11 CERAMIC CHIP 1000PF 5% 25V C101 1-162-962-11 CERAMIC CHIP 470PF 10% 50V C102 1-162-962-11 CERAMIC CHIP 470PF 10% 50V (FX467) C103 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V C104 1-126-153-11 ELECT 22uF 20% 6.3V C105 1-115-156-11 CERAMIC CHIP 1uF 10V C106 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C107 1-115-156-11 CERAMIC CHIP 1uF 10V C108 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C201 1-162-962-11 CERAMIC CHIP 470PF 10% 50V C202 1-162-962-11 CERAMIC CHIP 470PF 10% 50V (FX467) C203 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V C204 1-126-153-11 ELECT 22uF 20% 6.3V C205 1-115-156-11 CERAMIC CHIP 1uF 10V C206 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C207 1-115-156-11 CERAMIC CHIP 1uF 10V C208 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C301 1-115-156-11 CERAMIC CHIP 1uF 10V C302 1-115-156-11 CERAMIC CHIP 1uF 10V C303 1-126-514-11 ELECT 22uF 20% 6.3V C304 1-164-360-11 CERAMIC CHIP 0.1uF 16V C305 1-126-514-11 ELECT 22uF 20% 6.3V C306 1-117-863-11 CERAMIC CHIP 0.47uF 10% 6.3V C307 1-164-492-11 CERAMIC CHIP 0.15uF 10% 16V C308 1-115-873-11 ELECT 3.3uF 20% 50V C309 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V C310 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C311 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C401 1-115-416-11 CERAMIC CHIP 1000PF 5% 25V C402 1-164-505-11 CERAMIC CHIP 2.2uF 16V C403 1-162-974-11 CERAMIC CHIP 0.01uF 50V C404 1-126-514-11 ELECT 22uF 20% 6.3V C405 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V C406 1-162-995-11 CERAMIC CHIP 0.022uF 50V C501 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C502 1-126-514-11 ELECT 22uF 20% 6.3V C503 1-126-176-11 ELECT 220uF 20% 10V C601 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C602 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V C603 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V C604 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V C605 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V C606 1-117-863-11 CERAMIC CHIP 0.47uF 10% 6.3V C607 1-125-838-91 CERAMIC CHIP 2.2uF 10% 6.3V C701 1-164-361-11 CERAMIC CHIP 0.047uF 16V C702 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V C703 1-162-917-11 CERAMIC CHIP 15PF 5% 50V C704 1-162-917-11 CERAMIC CHIP 15PF 5% 50V C705 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C707 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V C708 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V C709 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V MAIN www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 25 – C710 1-117-863-11 CERAMIC CHIP 0.47uF 10% 6.3V C711 1-104-847-11 TANTAL. CHIP 22uF 20% 4V C712 1-126-916-11 ELECT 1000uF 20% 6.3V C714 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C715 1-115-416-11 CERAMIC CHIP 1000PF 5% 25V < TRIMMER > CT1 1-141-422-11 CAP, ADJ 10PF(AM TRACKING) < DIODE > D1 8-759-072-60 DIODE SVC347T-TL D2 8-719-053-30 DIODE MA357(E)-(TX).SO D3 8-719-053-30 DIODE MA357(E)-(TX).SO D4 8-719-053-30 DIODE MA357(E)-(TX).SO D401 8-719-420-87 DIODE MA8130-TX D402 8-719-073-01 DIODE MA111-(K8).S0 D703 8-719-049-09 DIODE 1SS367-T3SONY < FERRITE BEAD > FB101 1-500-245-11 INDUCTOR CHIP FB201 1-500-245-11 INDUCTOR CHIP FB301 1-500-245-11 INDUCTOR CHIP FB302 1-414-760-21 INDUCTOR CHIP < IC > IC1 8-752-073-35 IC CXA1960Q IC301 8-759-665-91 IC LB8115W-NA-TLM IC301 8-759-668-30 IC LB8115W-NB-TLM IC701 8-759-457-70 IC XC62RP1602MR IC702 8-759-664-42 IC LC72348W-CFX1705 < JACK > J301 1-565-287-11 JACK (i) < JUMPER RESISTOR > JR1 1-216-864-11 MATEL CHIP 0 5% 1/6W JR2 1-216-864-11 MATEL CHIP 0 5% 1/6W < COIL > L1 1-412-967-31 INDUCTOR 0.1uH L2 1-412-967-31 INDUCTOR 0.1uH L3 1-754-124-11 ANTENNA, FERRITE-ROD (AM TRACKING) L4 1-419-541-11 COIL, RF (FM)(FM TRACKING) L5 1-419-542-11 COIL, RF (TV)(TV TRACKING) L6 1-469-781-21 INDUCTOR 30nH L7 1-419-540-11 COIL, OSCILLATION (AM) (AM FREQUENCY COVERAGE) L401 1-412-991-11 INDUCTOR 10uH L702 1-412-995-21 INDUCTOR 22uH < TRANSISTOR > Q3 8-729-423-52 TRANSISTOR 2SC3931-C-TX Q301 8-729-422-54 TRANSISTOR XN4215-TX Q401 8-729-602-21 TRANSISTOR 2SC4154TP-1EF Q501 8-729-046-89 TRANSISTOR 2SB970-S(TX).S0 Q502 8-729-402-13 TRANSISTOR XN1501-TX Q701 8-729-046-89 TRANSISTOR 2SB970-S(TX).S0 < RESISTOR > R3 1-216-825-11 METAL CHIP 2.2K 5% 1/16W R4 1-216-817-11 METAL CHIP 470 5% 1/16W R5 1-216-833-91 RES-CHIP 10K 5% 1/16W R6 1-216-823-11 METAL CHIP 1.5K 5% 1/16W R7 1-216-833-91 RES-CHIP 10K 5% 1/16W R8 1-216-833-91 RES-CHIP 10K 5% 1/16W R9 1-216-864-11 METAL CHIP 0 5% 1/16W R10 1-216-833-91 RES-CHIP 10K 5% 1/16W R11 1-216-833-91 RES-CHIP 10K 5% 1/16W R12 1-216-803-11 METAL CHIP 33 5% 1/16W R13 1-216-813-11 METAL CHIP 220 5% 1/16W R14 1-216-825-11 METAL CHIP 2.2K 5% 1/16W R15 1-216-845-11 METAL CHIP 100K 5% 1/16W R16 1-216-845-11 METAL CHIP 100K 5% 1/16W R17 1-216-833-91 METAL CHIP 10K 5% 1/16W R18 1-216-845-11 METAL CHIP 100K 5% 1/16W R19 1-216-833-91 RES-CHIP 10K 5% 1/16W R20 1-216-821-11 METAL CHIP 1K 5% 1/16W R101 1-216-835-11 METAL CHIP 15K 5% 1/16W R102 1-216-835-11 METAL CHIP 15K 5% 1/16W R103 1-216-855-11 METAL CHIP 680K 5% 1/16W R104 1-216-819-11 METAL CHIP 680 5% 1/16W R105 1-216-815-11 METAL CHIP 330 5% 1/16W R106 1-216-831-11 METAL CHIP 6.8K 5% 1/16W R107 1-216-864-11 METAL CHIP 0 5% 1/16W R201 1-216-835-11 METAL CHIP 15K 5% 1/16W R202 1-216-835-11 METAL CHIP 15K 5% 1/16W R203 1-216-855-11 METAL CHIP 680K 5% 1/16W R204 1-216-819-11 METAL CHIP 680 5% 1/16W R205 1-216-815-11 METAL CHIP 330 5% 1/16W R206 1-216-831-11 METAL CHIP 6.8K 5% 1/16W R207 1-216-864-11 METAL CHIP 0 5% 1/16W R301 1-216-829-11 METAL CHIP 4.7K 5% 1/16W R302 1-216-789-11 METAL CHIP 2.2 5% 1/16W R303 1-216-845-11 METAL CHIP 100K 5% 1/16W R304 1-216-821-11 METAL CHIP 1K 5% 1/16W R305 1-216-849-11 METAL CHIP 220K 5% 1/16W R401 1-216-821-11 METAL CHIP 1K 5% 1/16W R402 1-216-813-11 METAL CHIP 220 5% 1/16W R403 1-216-845-11 METAL CHIP 100K 5% 1/16W R501 1-216-819-11 METAL CHIP 680 5% 1/16W R502 1-216-829-11 METAL CHIP 4.7K 5% 1/16W R503 1-216-833-91 RES-CHIP 10K 5% 1/16W R504 1-216-847-11 METAL CHIP 150K 5% 1/16W R601 1-216-821-11 METAL CHIP 1K 5% 1/16W R602 1-216-835-11 METAL CHIP 15K 5% 1/16W R603 1-216-821-11 METAL CHIP 1K 5% 1/16W R604 1-216-845-11 METAL CHIP 100K 5% 1/16W R605 1-216-821-11 METAL CHIP 1K 5% 1/16W R606 1-216-821-11 METAL CHIP 1K 5% 1/16W R607 1-216-833-91 RES-CHIP 10K 5% 1/16W R701 1-216-845-11 METAL CHIP 100K 5% 1/16W R702 1-216-829-11 METAL CHIP 4.7K 5% 1/16W R703 1-216-845-11 METAL CHIP 100K 5% 1/16W R704 1-216-841-11 METAL CHIP 47K 5% 1/16W R705 1-216-847-11 METAL CHIP 150K 5% 1/16W Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark MAIN www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 26 – WM-FX277/FX467/FX467ST 9-927-695-11 Sony Corporation Personal Audio Division Company 2000C0214-1 Printed in Japan © 2000.3 Published by General Engineering Dept. R706 1-216-845-11 METAL CHIP 100K 5% 1/16W R707 1-216-845-11 METAL CHIP 100K 5% 1/16W R708 1-216-849-11 METAL CHIP 220K 5% 1/16W R710 1-216-833-91 RES-CHIP 10K 5% 1/16W R711 1-216-833-91 RES-CHIP 10K 5% 1/16W R712 1-216-833-91 RES-CHIP 10K 5% 1/16W R713 1-216-833-91 RES-CHIP 10K 5% 1/16W R714 1-216-833-91 RES-CHIP 10K 5% 1/16W R715 1-216-833-91 RES-CHIP 10K 5% 1/16W R716 1-216-833-91 RES-CHIP 10K 5% 1/16W R717 1-216-857-11 METAL CHIP 1M 5% 1/16W R718 1-216-833-91 RES-CHIP 10K 5% 1/16W R720 1-216-833-91 RES-CHIP 10K 5% 1/16W R721 1-216-833-91 RES-CHIP 10K 5% 1/16W R722 1-216-845-11 METAL CHIP 100K 5% 1/16W < VARIABLE RESISTOR > RV1 1-223-994-21 RES, CARBON ADJ VAR 4.7K (FM VCO) RV2 1-223-998-21 RES, CARBON ADJ VAR 100K (AM IF) RV301 1-223-609-21 RES, VAR, CARBON 10K/10K (VOLUME ) RV601 1-241-784-11 RES, ADJ, CARBON 5K (TAPE SPEED) < SWITCH > S301 1-762-742-61 SWITCH, DETECTION (SMALL TYPE) (TAPE ON) S302 1-762-742-61 SWITCH, DETECTION (SMALL TYPE)(N/R SW) (FX467/FX467ST) S303 1-692-298-11 SWITCH, SLIDE (DX/LOCAL, METAL/NORM) S304 1-692-298-11 SWITCH, SLIDE (AVLS) S701 1-572-922-11 SWITCH, SLIDE (HOLD) < TRANSFORMER > T401 1-426-917-11 TRANSFORMER, DC-DC CONVERTER < THERMISTOR > TH601 1-803-751-21 THERMISTOR, POSITIVE < VIBRATOR > X701 1-579-615-11 VIBRATOR, CRYSTAL(75kHz) ************************************************************** MISCELLANEOUS ************** * 19 1-694-218-31 CONNECTOR, RUBBER L3 1-754-124-11 ANTENNA, FERRITE-ROD (AM TRACKING) ND701 1-803-944-11 PANEL, LIQUID CRYSTAL DISPLAY M601 1-763-073-11 MOTOR(CAPSTAN/REEL) (INCLUDING PULLY) HP601 1-500-641-11 HEAD, MAGNETIC (PLAYBACK) (FX277) HP601 1-500-648-11 HEAD, MAGNETIC (PLAYBACK) (FX467,FX467ST) ************************************************************** ACCESSORIES & PACKING MATERIALS ******************************** 3-046-064-01 CASE, CARRYING (FX277) 3-047-455-01 CASE, CARRYING (FX467,FX467ST) 3-868-004-11 MANUAL, INSTRUCTION (ENGLISH, SPANISH) 8-953-273-83 RECEIVER,EAR MDR-G051LP (FX467ST) 8-953-775-90 RECEIVER, EAR MDR-026LP (FX277,FX467) Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark MAIN www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com
