DATA PROJECTOR VPL-CS7 VPL-ES2 REMOTE COMMANDER RM-PJ2 SERVICE MANUAL 1st Edition www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com VPL-CS7/ES2 ! WARNING This manual is intended for qualified service personnel only. To reduce the risk of electric shock, fire or injury, do not perform any servicing other than that contained in the operating instructions unless you are qualified to do so. Refer all servicing to qualified service personnel. ! WARNUNG Die Anleitung ist nur für qualifiziertes Fachpersonal bestimmt. Alle Wartungsarbeiten dürfen nur von qualifiziertem Fachpersonal ausgeführt werden. Um die Gefahr eines elektrischen Schlages, Feuergefahr und Verletzungen zu vermeiden, sind bei Wartungsarbeiten strikt die Angaben in der Anleitung zu befolgen. Andere als die angegeben Wartungsarbeiten dürfen nur von Personen ausgeführt werden, die eine spezielle Befähigung dazu besitzen. ! AVERTISSEMENT Ce manual est destiné uniquement aux personnes compétentes en charge de l’entretien. Afin de réduire les risques de décharge électrique, d’incendie ou de blessure n’effectuer que les réparations indiquées dans le mode d’emploi à moins d’être qualifié pour en effectuer d’autres. Pour toute réparation faire appel à une personne compétente uniquement. WARNING!! AN INSULATED TRANSFORMER SHOULD BE USED DURING ANY SERVICE TO AVOID POSSIBLE SHOCK HAZARD, BE- CAUSE OF LIVE CHASSIS. THE CHASSIS OF THIS RECEIVER IS DIRECTLY CONNECTED TO THE AC POWER LINE. SAFETY-RELATED COMPONENT WARNING !! COMPONENTS IDENTIFIED BY A ! ! ! ! ! MARK ON THE SCHEMATIC DIAGRAMS, EXPLODED VIEWS AND IN THE PARTS LIST ARE CRITICAL TO SAFE OPERATION. REPLACE THESE COMPO- NENTS WITH SONY PARTS WHOSE PART NUMBERS APPEAR AS SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUB- LISHED BY SONY. CIRCUIT ADJUSTMENTS THAT ARE CRITI- CAL TO SAFE OPERATION ARE IDENTIFIED IN THIS MANUAL. FOLLOW THESE PROCEDURES WHENEVER CRITICAL COM- PONENTS ARE REPLACED OR IMPROPER OPERATION IS SUSPECTED. ATTENTION!! AFIN D’ÉVITER TOUT RISQUE D’ÉLECTROCUTION PROVENANT D’UN CHÂSSIS SOUS TENSION, UN TRANSFORMATEUR D’ISOLEMENT DOIT ETRE UTILISÉ LORS DE TOUT DÉPANNAGE. LE CHÂSSIS DE CE RÉCEPTEUR EST DIRECTEMENT RACCORDÉ Á L’ALIMENTATION SECTEUR. ATTENTION AUX COMPOSANTS RELATIFS Á LA SÉCURITÉ!! LES COMPOSANTS IDENTIFIÉS PAR UNE MAPQUE ! ! ! ! ! SUR LES SCHÉMAS DE PRINCIPE, LES VUES EXPLOSÉES ET LES LISTES DE PIECES SONT D’UNE IMPORTANCE CRITIQUE POUR LA SÉCURITÉ DU FONCTIONNEMENT. NE LES REMPLACER QUE PAR DES COMPOSANTS SONY DONT LE NUMÉRO DE PIÈCE EST INDIQUÉ DANS LE PRÉSENT MANUEL OU DANS DES SUPPLÉMENTS PUBLIÉS PAR SONY. LES RÉGLAGES DE CIRCUIT DONT L’IMPORTANCE EST CRITIQUE POUR LA SÉCURITÉ DU FONCTIONNEMENT SONT IDENTIFIÉS DANS LE PRÉSENT MANUEL. SUIVRE CES PROCÉDURES LORS DE CHAQUE REMPLACEMENT DE COMPOSANTS CRITIQUES, OU LORSQU’UN MAUVAIS FONCTIONNEMENT EST SUSPECTÉ. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com VPL-CS7/ES2 For the customers in the Netherlands Voor de klanten in Nederland Hoe u de batterijen moet verwijderen, leest u in de tekst van deze handleiding. Gooi de batterij niet weg maar lever deze in als klein chemisch afval (KCA). Für Kunden in Deutschland Entsorgungshinweis: Bitte werfen Sie nur entladene Batterien in die Sammelboxen beim Handel oder den Kommunen. Entladen sind Batterien in der Regel dann, wenn das Gerät abschaltet und signalisiert “Batterie leer” oder nach längerer Gebrauchsdauer der Batterien “nicht mehr einwandfrei funktioniert”. Um sicherzugehen, kleben Sie die Batteriepole z.B. mit einem Klebestreifen ab oder geben Sie die Batterien einzeln in einen Plastikbeutel. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 1 VPL-CS7/ES2 Table of Contents 1. Service Overview 1-1. Appearance Figure ......................................................................................1-1 1-2. Board Locations ..........................................................................................1-1 1-3. Disassembly ................................................................................................1-2 1-3-1. Top Panel Assembly ..................................................................1-2 1-3-2. H Board ......................................................................................1-2 1-3-3. C Board ......................................................................................1-3 1-3-4. Lens Gear ...................................................................................1-4 1-3-5. Fan Holder..................................................................................1-4 1-3-6. D.C. Fan (60 mm) and D.C. Fan (70 mm) ................................1-5 1-3-7. Lamp House ...............................................................................1-5 1-3-8. Optics Block Assembly ..............................................................1-6 1-3-9. Prism Block Assembly ...............................................................1-6 1-3-10. Incidence Polarizer (R), (G), (B)................................................1-7 1-3-11. Side Panel Assembly-1 ..............................................................1-8 1-3-12. Side Panel Assembly-2 ..............................................................1-9 1-3-13. G Board ....................................................................................1-10 1-3-14. Lamp Power Supply .................................................................1-10 1-3-15. D.C. Fan (Sirocco/For Lamp) ..................................................1-11 1-3-16. D.C. Fan (Sirocco) ...................................................................1-12 1-3-17. Adjuster Block Assembly ........................................................1-13 1-4. Note on Power Cord ..................................................................................1-14 2. Electrical Adjustments 2-1. Preparation ..................................................................................................2-1 2-1-1. Required Equipment...................................................................2-1 2-1-2. Opt Unit Adjustment ..................................................................2-1 2-1-3. How to Enter the Factory Mode .................................................2-2 2-2. V COM Adjustment ....................................................................................2-2 2-3. Initial Values of Adjustment Items .............................................................2-3 2-4. Service Know-How ...................................................................................2-13 2-4-1. When the Prism Block is Replaced ..........................................2-13 2-4-2. When the C Board is Replaced ................................................2-13 2-5. White Balance Adjustment .......................................................................2-14 2-5-1. HIGH Mode of INPUT-A ........................................................2-14 2-5-2. LOW Mode of INPUT-A .........................................................2-14 2-5-3. HIGH Mode of VIDEO............................................................2-14 2-5-4. LOW Mode of VIDEO.............................................................2-14 2-6. Memory Structure .....................................................................................2-15 3. Semiconductors www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 2 VPL-CS7/ES2 4. Spare Parts 4-1. Notes on Repair Parts ..................................................................................4-1 4-2. Exploded Views ..........................................................................................4-2 4-3. Electrical Parts List .....................................................................................4-6 5. Block Diagrams Overall .........................................................................................................5-1 G ..................................................................................................................5-2 H ..................................................................................................................5-3 L ..................................................................................................................5-3 NR ...............................................................................................................5-3 SA................................................................................................................5-3 V ..................................................................................................................5-3 6. Schematic Diagrams C ..................................................................................................................6-2 G ................................................................................................................ 6-15 H ................................................................................................................ 6-17 NR .............................................................................................................6-18 QA (VPL-ES2) ..........................................................................................6-18 Q (VPL-CS7) ............................................................................................6-18 SA.............................................................................................................. 6-19 S.................................................................................................................6-19 V ................................................................................................................ 6-19 Frame Wiring ............................................................................................6-20 7. Board Layouts C ..................................................................................................................7-2 G ..................................................................................................................7-4 H ..................................................................................................................7-5 L ..................................................................................................................7-5 NR ...............................................................................................................7-5 QA (VPL-ES2) ............................................................................................7-5 Q (VPL-CS7) ..............................................................................................7-5 SA................................................................................................................7-6 S...................................................................................................................7-7 V ..................................................................................................................7-7 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 1-1 VPL-CS7/ES2 Section 1 Service Overview 1-1. Appearance Figure 1-2. Board Locations QA (For VPL-ES2) Q (For VPL-CS7) C V SA G L NR H Lamp power supply VPL-CS7/ES2 RM-PJ2 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 1-2 VPL-CS7/ES2 1-3. Disassembly 1-3-1. Top Panel Assembly 1 Five special screws (+BV3 x 70) 6 Remove the top panel assembly in the direction of the arrow. 2 Screw (+PSW3 x 8) C board 3 Three claws 4 Ten claws 1 Five claws 3 Top panel 5 Flat connector assembly (CN805) 8 H board 4 Flat connector assembly 6 Holder (H) 7 Button (H) 2 Two dowels 5 Two claws CN10 1-3-2. H Board . Remove the top panel assembly. (Refer to 1-3-1.) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 1-3 VPL-CS7/ES2 1-3-3. C Board CN804 CN501 CN651 CN601 CN904 CN807 CN810 CN802 CN812 CN906 3 Four screws (+PSW3 x 8) 8 Hexagon screws 9 Bracket (C) 1 Remove the harneses. C board CN903 CN701 CN815 SA board CN702 A B B CN809 CN815 CN811 CN806 C 7 Screw (+PSW3 x 8) 0 Fuse connector assembly 2 Remove the fuse connector assembly. !- C board 6 Remove the C board in the direction of the arrow C. 4 Open the side panel assembly in the direction of the arrow A. 5 Remove the C board in the direction of the arrow B. Side panel shaft C board Side panel shaft C board www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 1-4 VPL-CS7/ES2 1-3-4. Lens Gear . Remove the C board. (Refer to 1-3-3.) 1-3-5. Fan Holder ZOOM/FOCUS ZOOM/FOCUS Fan holder 2 Open the side panel assembly in the direction of the arrow A. 4 Remove the Iens gear in the direction of the arrow B. 3 Two dowels A B 1 Screw (+PSW3 x 8) C board Lens gear Lens Engage the gears. 1 Two screws (+BVTP3 x 10) 5 Remove the fan holder while taking care so that it must not be caught by other parts. 4 Dowel 2 Remove the side panel assembly in the direction of the arrow A. 3 Remove the four claws in the direction of the arrow B. A B Side panel assembly www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 1-5 VPL-CS7/ES2 1-3-6. D.C. Fan (60 mm) and D.C. Fan (70 mm) . Remove the fan holder. (Refer to 1-3-5.) 1 Two grooves 4 Two grooves 2 D.C. fan (70 mm) 5 D.C. fan (60 mm) CN811 C board CN810 3 Remove the harnesses. 5 Lamp house C board 2 Two screws (+BTP3 x 10) 3 Lamp power supply 4 Screw (+BTP3 x 10) CN807 CN810 1 Remove the harness. 1-3-7. Lamp House . Remove the fan holder. (Refer to 1-3-5.) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 1-6 VPL-CS7/ES2 1-3-8. Optics Block Assembly . To remove the optics block assembly, remove the related parts beforehand. 4 Four screws (+BTP3 x 10) 5 Two dowels 6 Optics block assembly C board 1 C board • Remove the C board. (Refer to 1-3-3.) 3 Lamp house • Remove the lamp house. (Refer to 1-3-7.) 2 Fan holder • Remove the fan holder. (Refer to 1-3-5.) 1 Two precision screws (+B2 x 5) 3 Screw (+PTP2 x 8) 5 Radiation polarizer (R) assembly 6 Pre radiation polarizer (G) assembly 7 Radiation polarizer (G) assembly 9 Radiation polarizer (B) assembly 8 Pre radiation polarizer (B) assembly 4 Polarizer retainer 2 Prism block assembly 1-3-9. Prism Block Assembly . Remove the optics block assembly. (Refer to 1-3-8.) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 1-7 VPL-CS7/ES2 5 Incidence polarizer (B) assembly 3 Incidence polarizer (R) assembly 4 Incidence polarizer (G) assembly 2 Unit cover 1 Six screws (+BTP3 x 10) 1-3-10. Incidence Polarizer (R), (G), (B) . Remove the optics unit assembly. (Refer to 1-3-8.) . Remove the prism block assembly. (Refer to 1-3-9.) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 1-8 VPL-CS7/ES2 CN804 CN501 CN651 CN601 CN807 CN810 CN802 CN812 CN906 2 Four screws (+PSW3 x 8) 5 Screw (+PSW3 x 8) 6 Cover (G), Sheet (G) 1 Remove the harness. C board C board C board G board G board 3 Open the side panel assembly in the direction of the arrow A. 4 Remove the C board in the direction of the arrow B. A B B Side panel shaft Cover (G) Sheet (G) Cover (B) Cover (B2) 1-3-11. Side Panel Assembly-1 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 1-9 VPL-CS7/ES2 1 Open the side panel assembly in the direction of the arrow AB. 4 NR board 5 L board 9 Side panel assembly 6 Speaker bracket 8 Speaker assembly A C B Three claws Three claws Two claws Claw CN80 CN70 7 Sheet (SP) 3 Sheet (NR2) 2 Remove the side panel assembly in the direction of the arrow C. Note : Remove the side panel assembly while taking care so that it must not be caught by other parts. 1-3-12. Side Panel Assembly-2 . Remove the C board and cover (G). (Refer to 1-3-11.) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 1-10 VPL-CS7/ES2 1-3-13. G Board . Remove the cover (G), sheet (G). (Refer to 1-3-11) 1-3-14. Lamp Power Supply . Remove the cover (G), sheet (G). (Refer to 1-3-11) . Remove the G board. (Refer to 1-3-13.) C board 2 G board 4 Lamp power supply 1 Flat connector assembly CN201 CN1 CN2 CN102 CN101 C board 2 Two screws (+PSW3 x 8) 3 Sheet (B) 1 Two screws (+BTP3 x 10) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 1-11 VPL-CS7/ES2 C board 1 Two screws (+BTP3 x10) 2 Fan bracket 5 Remove the D.C. fan (Sirocco/For lamp) in the direction of the arrow. 3 Two dowels 6 D.C. fan (Sirocco/For lamp) Fan holder 4 Loosen the screw. 1-3-15. D.C. Fan (Sirocco/For Lamp) . Remove the side panel assembly-1,2. (Refer to 1-3-11, 12) . Remove the G board. (Refer to 1-3-13.) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 1-12 VPL-CS7/ES2 CN815 CN809 CN811 CN806 CN802 4 Three screws (+BTP3 x 10) 2 Three screws (+BTP3 x 10) 6 Fan holder 9 D.C. fan (Sirocco) 8 Two dowels 5 Remove the fan holder in the direction of the arrow. 3 SA board C board 7 Remove the harness. Dowel D.C. fan (Sirocco) 1 Remove the fuse connector assembly. 1-3-16. D.C. Fan (Sirocco) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 1-13 VPL-CS7/ES2 4 Optics block assembly . Remove the optics block assembly. (Refer to 1-3-8.) 5 Three screws (+BTP3 x 10) 7 Dowel 8 Remove the adjuster block assembly in the direction of the arrow. 6 Dowel 9 Adjuster block assembly 1 C board . Remove the C board. (Refer to 1-3-3.) 3 Lamp house . Remove the lamp house. (Refer to 1-3-7.) 2 Fan holder . Remove the fan holder. (Refer to 1-3-5.) 1-3-17. Adjuster Block Assembly . To remove the adjuster block assembly, remove the related parts beforehand. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 1-14 VPL-CS7/ES2 1-4. Note on Power Cord Warning on power connection Use a proper power cord for your local power supply. The United States, Continental Europe UK, Ireland, Japan Canada Australia, New Zealand Plug type VM0233 290B YP-12A COX-07 -(1) YP332 Connector type VM0089 386A YC-13B COX-02 VM0310B YC-13 Cord type SJT SJT H05VV-F H05VV-F N13237/CO-228 VCTF Rated Voltage/Current 10A/125V 10A/125V 10A/250V 10A/250V 10A/250V 7A/125V Safety approval UL/CSA UL/CSA VDE VDE VDE DENAN Cord length (max.) 4.5m (14 feet 9 inches) – (1) Use an appropriate rating plug which is applied to local regulations. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 2-1 VPL-CS7/ES2 Section 2 Electrical Adjustments 2-1. Preparation 2-1-1. Required Equipment . NTSC, PAL, SECAM component signal generator Tektronix TG2000 + AVG1 (option module) + AWVG1 (option module) or equivalent . VG (programmable video signal generator) VG854 or equivalent . Illuminance meter n Allow the warm-up time of 5 minutes after the power is on before starting the following adjustments. 2-1-2. Opt Unit Adjustment 1. Let the VPL-CS7/ES2 show the ALL WHITE screen. 2. Adjust the B-channel illumination adjustment mirror so that the yellow frame must not appear in any of top, bottom, right and left of the screen. 3. Tighten the adjustment plate fixing screw using a torque screwdriver. (Torque 0.19 ±0.03 Nm) 4. Adjust the G-channel illumination adjustment mirror so that the magenta frame must not appear in any of top, bottom, right and left of the screen. 5. Tighten the adjustment plate fixing screw using a torque screwdriver. (Torque 0.19 ±0.03 Nm) 6. Adjust the R-channel illumination adjustment mirror so that the cyan frame must not appear in any of top, bottom, right and left of the screen. 7. Tighten the adjustment plate fixing screw using a torque screwdriver. (Torque 0.19 ±0.03 Nm) When installing the optical unit in this model, alignment of the gear tooth position is required. Perform the following steps. Procedure 1. Rotate the lens focus and zoom in the fully clockwise positions. Lock the lens gear in the direction shown in Fig. 1. Fig. 1 2. Align the marking position of the zoom gear with the protrusion of the lens gear approximately by visual observation as shown below. Fig. 2 (inside view) Lens projection Lens gear Gear alignment portion Lens gear Lens gear Zoom Focus Lens gear Lens Engage the gears. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 2-2 VPL-CS7/ES2 2-2. V COM Adjustment 1. Connect the VG to the INPUT-A connector. Connect the FLAT FIELD 100 IRE signal to the input connec- tor. Leave the VPL-CS7/ES2 with POWER ON for 10 minutes or longer for aging. 2. Enter the Factory Mode. Enter the Device Adjust MENU, and then enter the Panel Drive Adjustment MENU. 3. Connect the SVGA, R-single color, 30 IRE, single-line ON/OFF signal to the input connector. 4. Enter the P. DRV Adjustment MENU, and then enter the VCOM R Adjustment screen. 5. Adjust the VCOM R value for minimum flicker. 6. Change the input signal to the SVGA, G-single color, 30 IRE, single-line ON/OFF signal, and connect it to the input connector. 7. Enter the P. DRV Adjustment MENU, and then enter the VCOM G Adjustment screen. 8. Adjust the VCOM G value for minimum flicker. 9. Change the input signal to the SVGA, B-single color, 30 IRE, single-line ON/OFF signal, and connect it to the input connector. 10. Enter the P. DRV Adjustment MENU, and then enter the VCOM B Adjustment screen. 11. Adjust the VCOM B value for minimum flicker. 12. Store the adjustment value in the memory. 13. Turn over the “Image flip” up side down and repeat the steps from 1 through 12. Confirmation Install the side panel and confirm that the portions A and B of the dial cannot be seen from the opening of the side panel when the ZOOM and FOCUS are moved to their very ends. 2-1-3. How to Enter the Factory Mode 1. Confirm that the MENU can be displayed. 2. Close the MENU. 3. Press the keys in the following order : [ENTER] → [ENTER] → [&] → [ENTER]. The message [Do you want to enter the Factory Mode? Yes : ↑ No : ↓] appears. Select [Yes : ↑]. [Supplementary information: How to Exit the Factory Mode] Perform the step 3 KEY operation. The message [Do you want to return to the User Mode? Yes : ↑ No : ↓] appears. Select [Yes : ↑]. n In the Factory mode, you can close the lens shutter if you keep pressing the TILT key even though the lamp lights. If the machine is left in this state for long hours, the lens shutter may melt in the worst case. Be sure to confirm that the lens shutter is not closed when the lamp lights in the Factory mode. B A ZOOM FOCUS ZOOM FOCUS Good No good www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 2-3 VPL-CS7/ES2 2-3. Initial Values of Adjustment Items VPL-CS7 Menu Title ItemName Picture Mode PICTURE SETTING INPUT SETTING SET SETTING MENU SETTING Adjust Picture... Contrast Brightness Color Hue Sharpness Gamma Mode Color Temp. Adjust Signal... Dot Phase H Size Shift Wide Mode Smart APA Auto Input Search Input-A Signal Sel. Color System Power Saving Illumination Status Scan Conv 90 80 90 80 90 80 40 50 40 50 40 50 50 50 50 50 50 50 50 50 50 50 50 50 High High Middle Middle Middle Middle _ _ _ _ Graphics Graphics Low Low Low Low High High Off Off Off Off Off Off On On 30 On Off Computer Auto Off On On Languege English Menu Position Center Menu Color White 15 (*) * * Volume Set Memory Status Memory Standard Dynamic Video Standard Dynamic S Video Picture Memory W/B Memory Standard Dynamic Input-A Standard High Video Low High Computer Low MemoryName Remark (Continued) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 2-4 VPL-CS7/ES2 Menu Title ItemName INSTALL SETTING INFORMATION W/B SETTING Tilt... V Keystone Auto Manual... 0 Image Flip Off Background Blue Lamp Mode Standard High Altitude Off Security Lock Off Key Enter x 4 fH Dispaly only fV Dispaly only (Memory No.) Dispaly only (Resolution) Dispaly only Lamp Timer Dispaly only ROM Version Dispaly only SC ROM Version Dispaly only Operation Timer Dispaly only Prev. Lamp Timer Dispaly only Gain R G B Bias R G B 185 205 190 125 100 115 195 185 190 125 100 115 150 140 150 127 127 127 150 140 140 127 127 127 Set Memory Status Memory Dynamic Video Standard Dynamic S Video Picture Memory W/B Memory Standard Dynamic Input-A Standard High Video Low High Computer Low MemoryName Remark *: The “Dot Phase E, H Size, Shift H/V and Picture Mode” items in the “INPUT SETTING” menu have their respective initial values for each input signal (PRESET MEMORY No.). The “Picture Mode” items in the “PICTURE SETTING” menu have respective initial values for input signal (PRESET MEMORY No.). n There are some adjustment items that cannot be adjusted, depending on the input signal. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 2-5 VPL-CS7/ES2 Device Name ItemName Clamp Position Clamp Width R Gain (Other) R Gain (Component) R Gain (VideoGBR) G Gain (Other) G Gain (Component) G Gain (VideoGBR) B Gain (Other) B Gain (Component) B Gain (VideoGBR) R Offset (Other) R Offset (Component) R Offset (VideoGBR) G Offset (Other) G Offset (Component) G Offset (VideoGBR) B Offset (Other) B Offset (Component) B Offset (VideoGBR) Pre Coast Post Coast Bandwidth Dither Vd 10BitEn Secam Nbw Line2 A Sync Line2 H Sync Line2 Los Status 1 Status 2 A/D Converter ADC/ Chroma/ D.Comb Chroma/ Set Memory *1 *1 2 8 3 Display only Display only Status Memory NT358 /NT443 /BW60 Pal/Pal-M/N /Secam /BW50 Component (15k) Chroma Memory Channel Memory Image Flip Memory double- speed component HDTV (YP b Pr) HDTV (GBR) include double-speed Video 15 _ _ _ _ _ _ _ _ 126 2 1 1 15 7 31 2 1 1 15 7 31 2 1 1 15 7 31 _ _ _ _ _ _ _ _ 15 _ _ 15 _ _ _ _ _ 128 _ _ 128 _ _ 120 80 75 120 120 75 120 80 75 _ 128 128 128 _ 128 128 _ 128 128 128 128 15kRGB S Video Input- A Up/Down inversion possible Up/Down inversion not possible MemoryName Remark (Continued) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 2-6 VPL-CS7/ES2 Device Name ItemName Offset R Offset G Offset B V Common R V Common G V Common B Psig 1 R Psig 1 G Psig 1 B Psig 2 R Psig 2 G Psig 2 B Signal Center R Signal Center G Signal Center B Gain R Gain G Gain B SH1 V Com Ptn Enb Installation Through SW FSEL CYD HST Position HST Phase HST Width Thresh Lamp Thresh Panel Thresh Atmos Hi Alt Const High Alt Cofe Cont Max Speed Max Speed Min Cont Slope Panel Driver Other P.Drv SH/ Other/ 3D Gamma DRC/ Other/ Temp/ Fan/ Fan1/ Set Memory 17 17 17 83 83 83 32 32 32 154 154 154 28 Non adjustable Non adjustable 0 1 1 2 903 69 0 Status Memory NT358 /NT443 /BW60 Pal/Pal-M/N /Secam /BW50 Component (15k) Chroma Memory Channel Memory Image Flip Memory double- speed component HDTV (YP b Pr) HDTV (GBR) include double-speed Video 122 122 122 122 122 122 92 92 92 92 92 92 Non adjustable Non adjustable Non adjustable Non adjustable Non adjustable Non adjustable Non adjustable Non adjustable Non adjustable Non adjustable Non adjustable Non adjustable Non adjustable Non adjustable Non adjustable Non adjustable Non adjustable Non adjustable 15kRGB S Video Input- A Up/Down inversion possible Up/Down inversion not possible MemoryName Remark (Continued) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 2-7 VPL-CS7/ES2 Device Name Other ItemName Cont Max Speed Max Speed Min Cont Slope Cont Max Speed Max Speed Min Cont Slope Synchronous Tilt C0 Tilt C1 Tilt C2 X Tilt Y Tilt TL TP TA Gamma Fan2/ Fan3/ Other/ 1 Factory adj. value Factory adj. value Factory adj. value Display only Display only Display only Display only Display only Factory adj. value Set Memory Status Memory NT358 /NT443 /BW60 Pal/Pal-M/N /Secam /BW50 Component (15k) Chroma Memory Channel Memory Image Flip Memory double- speed component HDTV (YP b Pr) HDTV (GBR) include double-speed Video Non adjustable Non adjustable Non adjustable Non adjustable Non adjustable Non adjustable Non adjustable Non adjustable Non adjustable Non adjustable Non adjustable Non adjustable Non adjustable Non adjustable Non adjustable Non adjustable 15kRGB S Video Input- A Up/Down inversion possible Up/Down inversion not possible MemoryName Remark n There are some adjustment items that cannot be adjusted, depending on the input signal. *1: The value changes depending on the color systems and input terminals. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 2-8 VPL-CS7/ES2 MenuTitle ItemName Picture Mode PICTURE SETTING INPUT SETTING SET SETTING MENU SETTING INSTALL SETTING INFORMATION W/B SETTING Adjust Picture... Contrast Brightness Color Hue Sharpness Black Level Adi. Gamma Mode Color Temp. Adjust Signal... Dot Phase H Size Shift Wide Mode Smart APA Auto Input Search Input-A Signal Sel. Color System Power Saving Illumination Status Scan Conv 90 80 90 90 75 85 60 50 60 55 50 55 50 50 65 60 55 50 50 50 50 50 50 50 High Off Off High High High High High _ _ _ _ _ _ High Low High Low Off Off Low Low Low High Off Off Off Off On Off 30 On Off Computer Auto Off On On Languege English Menu Position Center Menu Color White Tilt... V Keystone Auto Manual... 0 Image Flip Off Background Blue Lamp Mode Standard High Altitude Off Security Lock Off Key Enter x 4 fH Dispaly only fV Dispaly only (Memory No.) Dispaly only (Resolution) Dispaly only Lamp Timer Dispaly only ROM Version Dispaly only SC ROM Version Dispaly only Operation Timer Dispaly only Prev. Lamp Timer Dispaly only Gain R G B Bias R G B 15 (*) * * Volume Set Memory Status Memory * Dynamic Video Standard Game Picture Memory Living Cinema Presentation 90 80 90 90 75 85 60 50 60 55 50 55 50 50 65 60 55 50 50 50 50 50 50 50 Middle Off Off Middle Middle Middle Middle Middle _ _ _ _ _ _ High Low High Low Off Off Low Low Low High Off Off Off Off On Off Dynamic S Video Standard Game Living Cinema Presentation MemoryName VPL-ES2 (Continued) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 2-9 VPL-CS7/ES2 MenuTitle ItemName Picture Mode PICTURE SETTING INPUT SETTING SET SETTING MENU SETTING INSTALL SETTING INFORMATION W/B SETTING Adjust Picture... Contrast Brightness Color Hue Sharpness Black Level Adi. Gamma Mode Color Temp. Adjust Signal... Dot Phase H Size Shift Wide Mode Smart APA Auto Input Search Input-A Signal Sel. Color System Power Saving Illumination Status Scan Conv 90 80 90 90 75 85 60 50 60 55 50 55 50 50 65 60 55 50 50 50 50 50 50 50 Middle Off Off Middle Middle Middle Middle Middle Graphics Graphics Graphics Graphics Graphics Graphics High High High Low Off Off Low Low Low High Off Off Off Off On Off Languege Menu Position Menu Color Tilt... V Keystone Manual... Image Flip Background Lamp Mode High Altitude Security Lock Key fH fV (Memory No.) (Resolution) Lamp Timer ROM Version SC ROM Version Operation Timer Prev. Lamp Timer Gain R G B Bias R G B 150 140 150 127 127 127 150 140 140 127 127 127 150 140 150 127 127 127 150 140 140 127 127 127 Volume Dynamic Input-A Standard Game Picture Memory W/B Memory Living Cinema Presentation 90 80 90 90 75 85 60 50 60 55 50 55 50 50 65 60 55 50 50 50 50 50 50 50 Middle Off Off Middle Middle Middle Middle Middle Graphics Graphics Graphics Graphics Graphics Graphics High Low High Low Off Off Low Low Low High Off Off Off Off On Off On On On On On On On On On On On On Dynamic Component Standard Game Living Cinema Presentation High Video Low High Computer Low MemoryName Remark *: The “Dot Phase E, H Size, Shift H/V and Picture Mode” items in the “INPUT SETTING” menu have their respective initial values for each input signal (PRESET MEMORY No.). The “Picture Mode” items in the “PICTURE SETTING” menu have respective initial values for input signal (PRESET MEMORY No.). n There are some adjustment items that cannot be adjusted, depending on the input signal. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 2-10 VPL-CS7/ES2 Device Name ItemName Clamp Position Clamp Width R Gain (Other) R Gain (Component) R Gain (VideoGBR) G Gain (Other) G Gain (Component) G Gain (VideoGBR) B Gain (Other) B Gain (Component) B Gain (VideoGBR) R Offset (Other) R Offset (Component) R Offset (VideoGBR) G Offset (Other) G Offset (Component) G Offset (VideoGBR) B Offset (Other) B Offset (Component) B Offset (VideoGBR) Pre Coast Post Coast Bandwidth Dither Vd 10BitEn Secam Nbw Line2 A Sync Line2 H Sync Line2 Los Status 1 Status 2 A/D Converter ADC/ Chroma/ D.Comb Chroma/ Set Memory *1 *1 2 8 3 Display only Display only Status Memory NT358 /NT443 /BW60 Pal/Pal-M/N /Secam /BW50 Component (15k) Chroma Memory Channel Memory Image Flip Memory double- speed component HDTV (YP b Pr) HDTV (GBR) include double-speed Video Component 15 _ _ _ _ _ _ _ _ 126 2 1 1 15 7 31 2 1 1 15 7 31 2 1 1 15 7 31 _ _ _ _ _ _ _ _ 15 _ _ 15 _ _ _ _ _ 128 _ _ 128 _ _ 120 80 75 120 120 75 120 80 75 _ 128 128 128 _ 128 128 _ 128 120 80 75 120 120 75 120 80 75 _ 128 128 128 _ 128 128 _ 128 128 128 128 15kRGB S Video Input- A Up/Down inversion possible Up/Down inversion not possible MemoryName Remark (Continued) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 2-11 VPL-CS7/ES2 Device Name ItemName Offset R Offset G Offset B V Common R V Common G V Common B Psig 1 R Psig 1 G Psig 1 B Psig 2 R Psig 2 G Psig 2 B Signal Center R Signal Center G Signal Center B Gain R Gain G Gain B SH1 V Com Ptn Enb Installation Through SW FSEL CYD HST Position HST Phase HST Width Thresh Lamp Thresh Panel Thresh Atmos Hi Alt Const High Alt Cofe Cont Max Speed Max Speed Min Cont Slope Panel Driver Other P.Drv SH/ Other/ 3D Gamma DRC/ Other/ Temp/ Fan/ Fan1/ Set Memory 17 17 17 83 83 83 32 32 32 154 154 154 28 Non adjustable Non adjustable 0 1 1 2 903 69 0 Status Memory NT358 /NT443 /BW60 Pal/Pal-M/N /Secam /BW50 Component (15k) Chroma Memory Channel Memory Image Flip Memory double- speed component HDTV (YP b Pr) HDTV (GBR) include double-speed Video Component 122 122 122 122 122 122 92 92 92 92 92 92 Non adjustable Non adjustable Non adjustable Non adjustable Non adjustable Non adjustable Non adjustable Non adjustable Non adjustable Non adjustable Non adjustable Non adjustable Non adjustable Non adjustable Non adjustable Non adjustable Non adjustable Non adjustable 15kRGB S Video Input- A Up/Down inversion possible Up/Down inversion not possible MemoryName Remark (Continued) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 2-12 VPL-CS7/ES2 Device Name Other ItemName Cont Max Speed Max Speed Min Cont Slope Cont Max Speed Max Speed Min Cont Slope Synchronous Tilt C0 Tilt C1 Tilt C2 X Tilt Y Tilt TL TP TA Gamma Fan2/ Fan3/ Other/ 1 Factory adj. value Factory adj. value Factory adj. value Display only Display only Display only Display only Display only Factory adj. value Set Memory Status Memory NT358 /NT443 /BW60 Pal/Pal-M/N /Secam /BW50 Component (15k) Chroma Memory Channel Memory Image Flip Memory double- speed component HDTV (YP b Pr) HDTV (GBR) include double-speed Video Component Non adjustable Non adjustable Non adjustable Non adjustable Non adjustable Non adjustable Non adjustable Non adjustable Non adjustable Non adjustable Non adjustable Non adjustable Non adjustable Non adjustable Non adjustable Non adjustable 15kRGB S Video Input- A Up/Down inversion possible Up/Down inversion not possible MemoryName Remark n There are some adjustment items that cannot be adjusted, depending on the input signal. *1: The value changes depending on the color systems and input terminals. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 2-13 VPL-CS7/ES2 2-4. Service Know-How 2-4-1. When the Prism Block is Replaced 1. Perform the V COM adjustment. (Refer to Section “2- 2. VCOM Adjustment”.) 2. Write the GAMMA data of the prism block. 3. Perform the white balance adjustment. (Refer to Section “2-5. White Balance Adjustment”.) 2-4-2. When the C Board is Replaced n If any board other than the C board is replaced, it needs no adjustment. When the C board is replaced 1. Install the IC406 that was removed from the old C board, into the new C board. 2. Enter the Factory Mode. 3. Press the TILT key on the flat workbench. Stop pressing the TILT key at the position where the lens shutter becomes invisible when viewed from the front of the VPL-CS7/ES2. 4. Press the TILT 4 key until the “[value that is dis- played in step 3] + [+10] value is obtained. 5. Press the keys in following order. ENTER → ENTER → POSITION + → MEMORY keys (Memorizing the adjustment value) 6. Press the TILT 4 key until the adjuster does not touch the floor and at the same time the lens shutter is fully opened. 7. Press the MENU key to display the menu. Press the ↓ key and enter the Device Adjust Menu. 8. Enter the Other MENU and let the message “38 Other/ X TILT xxxx” (xxxx is any value) on screen. 9. Enter the X TILT value while the VPL-CS7/ES2 is set in the horizontal position, in “35 Other/TILT CO”. 10. Turn the VPL-CS7/ES2 so that it faces upward in the vertical position. Enter the X TILT value in the vertical position, in “36 Other/TILT C1”. 11. Turn the VPL-CS7/ES2 so that it faces downward in the vertical position. Enter the X TILT value in the vertical position, in “37 Other/TILT C2”. 12. Press the MEMORY key and save the adjustment value. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 2-14 VPL-CS7/ES2 2. In the LOW mode of W/B, adjust the GAIN R for +15 higher than the value in the HIGH mode, adjust the GAIN G for _25 lower than the value in the HIGH mode and adjust GAIN B that is the same as the value in the HIGH mode. 3. Measure the chromaticity (x, y). 4. Input the 30 IRE flat field signal. 5. Adjust the BIAS R and BIAS B in the LOW mode of W/B until the chromaticity (x, y) that is measured at step 3 is obtained. 6. Input the 80 IRE flat field signal. 7. Adjust the GAIN R and GAIN B in the LOW mode of W/B until the chromaticity (x, y) that is measured at step 3 is obtained. 8. Repeat steps 4 to 7 until the chromaticity (x ±0.002, y ±0.004) with reference to the chromaticity (x, y) that is measured at step 3 is obtained. 9. Press the MEMORY key and save the adjustment value. 2-5-3. HIGH Mode of VIDEO 1. Input the NTSC or PAL video signal to the input connector. 2. In the HIGH mode of W/B, adjust the GAIN R for _20 lower than the value in the INPUT-A HIGH mode, adjust the GAIN G for _35 lower than the value in the INPUT-A HIGH mode and adjust GAIN B that is the _20 lower than the value in the INPUT-A HIGH mode. 3. Adjust BIAS G for _5 lower than the value in the INPUT-A HIGH mode, adjust the BIAS R and BIAS B for the same value as those of the INPUT-A HIGH mode. 4. Press the MEMORY key and save the adjustment value. 2-5-4. LOW Mode of VIDEO 1. Input the NTSC or PAL video signal to the input connector. 2. In the LOW mode of W/B, adjust the GAIN R for _20 lower than the value in the INPUT-A LOW mode, adjust the GAIN G for _35 lower than the value in the INPUT-A LOW mode and adjust GAIN B that is the _20 lower than the value in the INPUT-A LOW mode. 3. Adjust BIAS G for _5 lower than the value in the INPUT-A LOW mode, adjust the BIAS R and BIAS B for the same value as those of the INPUT-A HIGH mode. 4. Press the MEMORY key for saving the adjustment value. 2-5. White Balance Adjustment Preparation before adjustment 1. Input the 100 IRE flat field signal to the INPUT-A connector and allow the warm-up of 10 minutes aging at a minimum. 2. Enter the Service Mode. Press the keys in the following order. [ENTER] → [ENTER] → [(] → [)] → [ENTER]. The message [Do you want to enter the Service Mode? Yes : ↑ No : ↓] appears. Select [Yes : ↑]. [Supplementary information: How to Exit the Service Mode] Perform the step 2 KEY operation. The message [Do you want to return to the User Mode?] Yes : ↑ No : ↓ appears. Select [Yes : ↑]. 2-5-1. HIGH Mode of INPUT-A Connect the10-step signal to the INPUT-A connector and measure the chromaticities at each brightness. If chromaticities are different at each brightness, perform the following adjustment. 1. Input the 100 IRE flat field signal to the INPUT-A connector. 2. Measure the chromaticity (x, y). 3. Input the 80 IRE flat field signal. 4. Adjust the GAIN R and GAIN B in the HIGH mode of W/B until the chromaticity (x, y) that is measured at step 2 is obtained. 5. Input the 30 IRE flat field signal. 6. Adjust the BIAS R and BIAS B in the HIGH mode of W/B until the chromaticity (x, y) that is measured at step 2 is obtained. 7. Repeat steps 3 to 6 until the chromaticity (x ±0.002, y ±0.004) with reference to the chromaticity (x, y) that is measured at step 2 is obtained. 8. Press the MEMORY key for saving the adjustment value. 2-5-2. LOW Mode of INPUT-A 1. Input the 80 IRE flat field signal to the INPUT-A connector. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 2-15 VPL-CS7/ES2 2-6. Memory Structure CPU internal ROM : 512 K byte Flash Memory CPU internal RAM : 32 K byte External NVM memory : 8 K byte EEPROM Set Memory Set Memory Set Memory Status Memory Picture Memory Status Memory No. 01 No. 02 No. 03 No. 04 No. 05 ... No. 99 Picture Memory Status Memory No. 01 No. 02 No. 03 No. 04 No. 05 ... ... No. 99 No. 101 No. 120 Input-A Component Preset Input-A User Video Dynamic Standard Game Living Cinema Presentation Dynamic Standard Game Living Cinema Presentation Dynamic Standard Game Living Cinema Presentation Dynamic Standard Game Living Cinema Presentation S Video Input-A Component Component Picture Memory Video Dynamic Standard Game Living Cinema Presentation Dynamic Standard Game Living Cinema Presentation Dynamic Standard Game Living Cinema Presentation Dynamic Standard Game Living Cinema Presentation S Video Input-A www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 2-16 VPL-CS7/ES2 Memory structure consists of the followings. 1 Set memory 2 Status memory 3 Picture memory 4 Chroma memory 5 W/B memory 6 Channel memory 7 Image Flip memory * The gamma memory is realized by giving offset to Contrast and Brightness output values to the devices in the gamma mode function. Flow of data is described briefly. When the power plug is connected to the wall outlet for the first time (Standby state), all data that are stored in the internal ROM are written in the NVM(non-volatile memo- ry). When the POWER is turned ON, all the status memory data and other memory data that are required for the present picture are selected from each memory block and expanded in the internal RAM. When any adjustment is performed at this moment, the adjustment data(user mode items) are written in the NVM(Service/Factory mode item) automatically triggered by the memory operation. The adjustment items(W/B, Device Adjust) that can be adjusted in the Service Mode or in the Factory mode, are memorized in the NVM at the time when the user performs adjustment and performs the memory operation. Note that the factory adjustment data will be lost at this moment. Chroma Memory Chroma Memory NT358/443/BW60 15k RGB Component (15k) Double-speed component HDTV (YPbPr) HDTV (GBR) includ.double-speed PAL/PAL-M/N/ SECAM/BW50 Chroma Memory NT358/443/BW60 15k RGB Component (15k) Double-speed component HDTV (YPbPr) HDTV (GBR) includ.double-speed PAL/PAL-M/N/ SECAM/BW50 Channel Memory Image Flip Memory W/B Memory Channel Memory Computer Others High Low High Low W/B Memory High Low Video S Video Input-A Component CPU ROM Initialize Memory Active memory copy External NVM CPU RAM Image Flip Memory Up/Down inversions impossible Up/Down inversions possible W/B Memory Channel Memory Computer Others High Low High Low Video S Video Input-A Component Image Flip Memory Up/Down inversions impossible Up/Down inversions possible www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 3-1 VPL-ES1 Section 3 Semiconductors IC 24LC21AT/SN CY25023SZC-1T HN58X24256FPIZ M24C64-WMN6T(B) SI4403DY-T1 SN75453BPS SN75453BPSR ST24FC21M6TR TC7WH125FK(TE85R) TC7WH34FU(TE12R) UPC393G2 UPC393G2-E2 1 TOP VIEW 8pin SOP 2SK219F04 1 3 2 ADXL202JE-REEL 1 2 3 4 8 5 INDEX 6 7 AIC1084-PEJTR 1 2 3 AIC1117A-18PYJTR AIC1117A-33PYJTR AIC1117A-50PYJTR 1 2 3 BA00ASFP-E2 GND 1 : IN 2 : GND 3 : OUT 1 2 3 BA00AST BA00AST-V5 1 2 3 4 5 BA09FP-E2 VCC GNDOUT BA6288FS-E2 MC74HC4052ADTR2 TC74HC4052AFT(EL) TPA2001D1PWR 1 TOP VIEW 16pin SOP CXA2171AQ CXA2171AQ-T6 CXA7005R-T4 1 TOP VIEW 48pin QFP CXD3536R 1 TOP VIEW 176pin QFP HD64F2376VFQ33V 1 TOP VIEW 144pin QFP LMC7101BIM5X TK11125CSCL-G 4 5 2 1 3 LTC1772CS6 1 TOP VIEW 6pin SOP M52347FP-TE SN74AHCT541PWR SN74LV244APWR TC74VHCT540AFT(EL) TDA7309D013TR 1 TOP VIEW 20pin SOP MAX4382EUD+TG069 SN74LV00APWR SN74LV02APWR TC74LCX125FT(EL) 1 TOP VIEW 14pin SOP MCZ3001U 1 TOP VIEW 32pin SOP MX29LV800ATTC-70G- 751PW100 1 TOP VIEW 48pin SOP PW168A-05VL BOTTOM VIEW 1 A 352pin PGA PW2200-05L PW2200A-05L 1 TOP VIEW 208pin QFP RS-140-T 1 2 3 4 TK11900MTL 1 6pin CHIP TL431CPK-E2 1 TOP VIEW 8pin DIP S-80928CNMC-G8YT2G 1 2 3 4 5 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 3-2 VPL-ES1 Transistor, Diode, LED 2SA1162-G 2SA1162-YG-TE85L 2SA1576A-T106-QR 2SC2712-YG 2SC2712-YG-TE85L 2SC4081-R 2SC4081T106R DTA114EUA-T106 DTC144EUA-T106 E B C 2SA1213Y-TE12L E B C 2SK2876-01MR-F122 GATE DRAIN SOURCE DTC114EU DTC114EUA-T106 GND IN OUT HN1B01FU-TE85R HN1C01FU-TE85R 5 6 4 1 3 2 4 5 6 2 1 3 SI4425DY-T1 S S S G D D D D SSM6N15FU(TE85R) S1 G1 D2 D1 G2 S2 XP4501-TXE 5 6 4 1 3 2 3 2 1 4 5 6 1SR154-400TE-25 D1FS4 D1FS4-TB D1FS4A-TA ANODE CATHODE 1SS355TE-17 EC31QS03L-TE12L MA111-(K8).S0 MA111-TX RD30SB-T1 RD39SB-T1 RD9.1SB2 RD9.1SB2-T1 CATHODE ANODE D10SC4M D10SC6M D10SC6M(RECTI) 1 2 3 1 2 3 D10XB80 DAN202U DAN202UT106 CATHODE ANODE NC FSF10A60 CATHODE ANODE HN1D03FU-TE85L HN1D03FU-TE85R 1 2 5 6 3 4 5 6 1 2 3 4 MA3J14700LSO CATHODE ANODE NNCD5.6LG-T1 1 5 4 3 2 1 5 4 3 2 RD18M-B1 RD18M-T1B1 1 2 3 1 2 3 RD3.9SB RD3.9SB-T1 UF4005PKG23 CATHODE ANODE RM11A RM11C(RECTI) CATHODE ANODE SEC1801C SEC1901C SEC2422C CATHODE MARK www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 4-1 VPL-CS7/ES2 4-1. Notes on Repair Parts 1. Safety Related Components Warning w Components marked ! are critical to safe operation. Therefore, specified parts should be used in the case of replacement. [WARNHINWEIS] [WARNHINWEIS] [WARNHINWEIS] [WARNHINWEIS] [WARNHINWEIS] Les composants identifiés par la marque ! sont critiques pour la sécurité. Ne les remplacer que par une pièce portant le numéro spécifié. 2. Standardization of Parts Some repair parts supplied by Sony differ from those used for the unit. These are because of parts common- ality and improvement. Parts List has the present standardized repair parts. 3. Stock of Parts Parts marked with “o” at SP (Supply Code) column of the Spare Parts list may not be stocked. Therefore, the delivery date will be delayed. Items with no part number and no description are not stocked because they are seldom required for routine service. 4. Units for Capacitors, Inductors and Resistors The following units are assumed in Schematic Dia- grams, Electrical Parts List and Exploded Views unless otherwise specified. Capacitors : µF Inductors : µH Resistors : Ω Section 4 Spare Parts www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 4-2 VPL-CS7/ES2 Cover 4-2. Exploded Views BTP3 x 10 4 9 9 9 10 9 9 9 2 7 6 8 5 3 1 A A B B No. Part No. SP Description 1 A-1061-840-A s MOUNTED CIRCUIT BOARD, NR 2 A-1061-845-A s MOUNTED CIRCUIT BOARD, SA (FOR VPL-CS7) A-1067-069-A s MOUNTED CIRCUIT BOARD, SA (FOR VPL-ES2) 3 A-1067-060-A s MOUNTED CIRCUIT BOARD, G 4 A-1067-061-A s MOUNTED CIRCUIT BOARD, C (FOR VPL-CS7) A-1067-062-A s MOUNTED CIRCUIT BOARD, C (FOR VPL-ES2) 5 A-1078-661-A s MOUNTED CIRCUIT BOARD, H 6 A-1078-662-A s MOUNTED CIRCUIT BOARD, L 7 ! A-1603-156-B s SPEAKER ASSY 8 ! 4-099-113-01 s FILTER (E1) 9 4-382-854-01 s SCREW +PSW M3X8(EP-FE/ZN/CM2) 10 4-099-122-01 s SCREW +BV3X70 TYPE2,SPECIAL www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 4-3 VPL-CS7/ES2 Chassis BTP3 x 10 BTP3 x 10 BTP3 x 10 BTP3 x 10 BTP3 x 10 BTP3 x 10 A A 101 107 104 103 105 106 102 No. Part No. SP Description 101 ! 1-468-803-11 s LAMP POWER SUPPLY 102 ! 1-787-065-21 s D.C. FAN (SIROCCO) 103 ! 1-787-078-11 s DC FAN 104 ! 1-787-079-11 s D.C. FAN (SIROCCO) 105 ! 1-787-080-11 s DC FAN 106 4-099-158-02 s HOUSE, LAMP(VPL-CS7) 4-099-158-11 s HOUSE, LAMP(VPL-ES2) 107 4-382-854-01 s SCREW +PSW M3X8(EP-FE/ZN/CM2) 7-685-547-19 s SCREW +BTP 3X10(EP-FE/ZNBK/CM2) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 4-4 VPL-CS7/ES2 Base PSW4 x 8 K3 x 6 205 208 208 203 201 204 202 BTP3 x 10 BTP3 x 10 A A BTP3 x 10 BTP3 x 10 +BTP 3x10 See Optics BTP3 x 10 207 206 No. Part No. SP Description 201 A-1061-842-A s MOUNTED CIRCUIT BOARD, Q (FOR VPL-CS7) A-1061-844-A s MOUNTED CIRCUIT BOARD, QA (FOR VPL-ES2) 202 A-1078-663-A s MOUNTED CIRCUIT BOARD, V 203 A-1078-675-A s ADJUSTOR BLOCK ASSY WITH MOUNT 204 A-1605-748-A s DC MOTOR ASSY, ADJUSTOR 205 ! 1-818-098-11 s INLET, AC (WITH NOISE FILTER) 206 2-050-785-01 s FOOT (C), REAR 207 4-096-049-01 s FOOT, FRONT 208 4-382-854-01 s SCREW +PSW M3X8(EP-FE/ZN/CM2) 7-682-247-09 s SCREW +K 3X6 7-682-951-01 s SCREW +PSW 3X14(EP-FE/ZN/CM2) 7-685-547-19 s SCREW +BTP 3X10(EP-FE/ZNBK/CM2) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 4-5 VPL-CS7/ES2 Optics 308 309 306 307 310 301 302 312 313 313 311 311 311 311 314 B2 x 5 PTP2 x 8 BVTP3 x 10 PS3 x 10 304 303 305 No. Part No. SP Description 301 A-1079-800-A s PRISM BLOCK ASSY (FOR VPL-CS7) A-1081-702-A s PRISM BLOCK ASSY (FOR VPL-ES2) 302 A-1079-798-A s OPT UNIT ASSY (FOR VPL-CS7) A-1081-700-A s OPT UNIT ASSY (FOR VPL-ES2) 303 A-1606-250-A s INCIDENCE POLARIZER (R) ASSY 304 A-1606-251-A s INCIDENCE POLARIZER (G) ASSY (FOR VPL-CS7) A-1606-634-A s IN-POLARIZATION (G) ASSY (FOR VPL-ES2) 305 A-1606-252-A s INCIDENCE POLARIZER (B) ASSY (FOR VPL-CS7) A-1606-635-A s IN-POLARIZATION (B) ASSY (FOR VPL-ES2) 306 A-1606-253-A s PRE RADIATION POLARIZER(G)ASSY (FOR VPL-CS7) A-1606-636-A s OUT-PRE-POLARIZER (G) ASSY (FOR VPL-ES2) 307 A-1606-254-A s PRE RADIATION POLARIZER(B)ASSY (FOR VPL-CS7) A-1606-637-A s OUT-PRE-POLARIZER (B) ASSY (FOR VPL-ES2) 308 A-1606-255-A s RADIATION POLARIZER (R) ASSY 309 A-1606-256-A s RADIATION POLARIZER (G) ASSY 310 A-1606-257-A s RADIATION POLARIZER (B) ASSY 311 4-089-523-01 s SPRING, LAMP 312 4-089-560-02 s LENS, CONCAVE 313 4-099-076-02 s SPRING, CONCAVE 314 A-1606-248-A s PROJECTION LENS ASSY 7-621-771-06 s SCREW +B2X5 7-685-105-19 s SCREW +PTP2X8(EP-FE/ZNBK/CM2) 7-685-647-79 s SCREW +BVTP3X10(EP-FE/ZNBK/CM2 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 4-6 VPL-CS7/ES2 4-3. Electrical Parts List -------------------- C BOARD ;For VPL-CS7 -------------------- Ref. No. or Q'ty Part No. SP Description 1pc A-1067-061-A s MOUNTED CIRCUIT BOARD, C C101 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C102 1-127-715-11 s CAPACITOR,CERAMIC 0.22MF B1608 C103 1-127-715-11 s CAPACITOR,CERAMIC 0.22MF B1608 C104 1-127-715-11 s CAPACITOR,CERAMIC 0.22MF B1608 C105 1-126-205-11 s CAPACITOR,ELECT 47MF/6.3 C106 1-126-205-11 s CAPACITOR,ELECT 47MF/6.3 C107 1-126-205-11 s CAPACITOR,ELECT 47MF/6.3 C108 1-126-205-11 s CAPACITOR,ELECT 47MF/6.3 C109 1-119-923-11 s CAPACITOR,CHIP CERAMIC 0.047MF C110 1-164-937-11 s CAPACITOR,CHIP CERAMIC 1000PF C111 1-135-995-91 s CAP,CHIP CERAMIC39000PF B 1608 C112 1-117-446-11 s CAPACITOR CERAMIC 3900PF 16V C113 1-119-923-11 s CAPACITOR,CHIP CERAMIC 0.047MF C114 1-119-923-11 s CAPACITOR,CHIP CERAMIC 0.047MF C115 1-126-205-11 s CAPACITOR,ELECT 47MF/6.3 C116 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C117 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C118 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C119 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C120 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C121 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C123 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C125 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C126 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C127 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C128 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C129 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C130 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C131 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C132 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C133 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C134 1-126-205-11 s CAPACITOR,ELECT 47MF/6.3 C136 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C137 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C138 1-126-205-11 s CAPACITOR,ELECT 47MF/6.3 C139 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C140 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C141 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C142 1-164-854-11 s CAPACITOR,CHIP CERAMIC 15PF/50 C143 1-164-854-11 s CAPACITOR,CHIP CERAMIC 15PF/50 C144 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C145 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C146 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C147 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C148 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C149 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C150 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C151 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C152 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C153 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C154 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C155 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C156 1-126-205-11 s CAPACITOR,ELECT 47MF/6.3 C157 1-126-205-11 s CAPACITOR,ELECT 47MF/6.3 C158 1-126-205-11 s CAPACITOR,ELECT 47MF/6.3 C201 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C205 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V (C BOARD ;For VPL-CS7) Ref. No. or Q'ty Part No. SP Description C206 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C207 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C208 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C209 1-117-720-11 s CAPACITOR, CERAMIC 4.7MF/10V F C210 1-164-937-11 s CAPACITOR,CHIP CERAMIC 1000PF C211 1-125-891-11 s CAPACITOR CERAMIC 0.47MF/10V C212 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C215 1-137-987-81 s CAPACITOR,C.CERAMIC 0.068MF C216 1-117-720-11 s CAPACITOR, CERAMIC 4.7MF/10V F C217 1-117-720-11 s CAPACITOR, CERAMIC 4.7MF/10V F C218 1-117-370-11 s CAPACITOR CERAMIC 10MF (3216) C220 1-127-715-11 s CAPACITOR,CERAMIC 0.22MF B1608 C221 1-125-837-91 s CAPACITOR,CHIP CERAMIC1MF/6.3V C223 1-127-715-11 s CAPACITOR,CERAMIC 0.22MF B1608 C224 1-125-891-11 s CAPACITOR CERAMIC 0.47MF/10V C225 1-164-943-11 s CAPACITOR,CHIP CERAMIC 0.01MF C227 1-164-874-11 s CAPACITOR,CHIP CERAMIC 100PF C228 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C229 1-164-882-11 s CAPACITOR,CERAMIC 220PF/16V CH C230 1-119-667-11 s CAPACITOR CERAMIC 22MF/10V(F) C231 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C232 1-125-837-91 s CAPACITOR,CHIP CERAMIC1MF/6.3V C233 1-164-943-11 s CAPACITOR,CHIP CERAMIC 0.01MF C234 1-164-943-11 s CAPACITOR,CHIP CERAMIC 0.01MF C236 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C237 1-107-826-11 s CAPACITOR,CHIP CERAMIC 0.1MF C238 1-125-837-91 s CAPACITOR,CHIP CERAMIC1MF/6.3V C239 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C242 1-117-720-11 s CAPACITOR, CERAMIC 4.7MF/10V F C243 1-117-720-11 s CAPACITOR, CERAMIC 4.7MF/10V F C301 1-119-667-11 s CAPACITOR CERAMIC 22MF/10V(F) C302 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C304 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C306 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C308 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C310 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C311 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C312 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C314 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C316 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C317 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C318 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C319 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C321 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C322 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C324 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C325 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C326 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C327 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C332 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C337 1-119-667-11 s CAPACITOR CERAMIC 22MF/10V(F) C339 1-164-852-11 s CAPACITOR,CHIP CERAMIC 12PF/50 C340 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C341 1-164-852-11 s CAPACITOR,CHIP CERAMIC 12PF/50 C342 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C343 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C344 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C345 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C347 1-119-667-11 s CAPACITOR CERAMIC 22MF/10V(F) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 4-7 VPL-CS7/ES2 (C BOARD ;For VPL-CS7) Ref. No. or Q'ty Part No. SP Description C348 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C349 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C350 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C351 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C352 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C353 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C354 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C355 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C356 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C357 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C358 1-119-667-11 s CAPACITOR CERAMIC 22MF/10V(F) C359 1-119-667-11 s CAPACITOR CERAMIC 22MF/10V(F) C361 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C363 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C364 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C365 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C367 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C368 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C369 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C370 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C371 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C372 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C373 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C379 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C380 1-164-852-11 s CAPACITOR,CHIP CERAMIC 12PF/50 C381 1-164-852-11 s CAPACITOR,CHIP CERAMIC 12PF/50 C401 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C402 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C403 1-117-370-11 s CAPACITOR CERAMIC 10MF (3216) C404 1-164-943-11 s CAPACITOR,CHIP CERAMIC 0.01MF C405 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C406 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C407 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C408 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C409 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C410 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C411 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C412 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C413 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C414 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C415 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C416 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C417 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C418 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C419 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C420 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C421 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C422 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C423 1-117-370-11 s CAPACITOR CERAMIC 10MF (3216) C426 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C427 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C428 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C429 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C430 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C431 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C432 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C433 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C435 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C436 1-126-205-11 s CAPACITOR,ELECT 47MF/6.3 (C BOARD ;For VPL-CS7) Ref. No. or Q'ty Part No. SP Description C437 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C438 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C439 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C441 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C442 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C443 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C444 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C445 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C501 1-119-667-11 s CAPACITOR CERAMIC 22MF/10V(F) C502 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C503 1-128-992-11 s CAPACITOR ELECT 47MF 25V C504 1-131-992-11 s CAP, CERAMIC 100000PF F 1608 C506 1-128-992-11 s CAPACITOR ELECT 47MF 25V C507 1-128-992-11 s CAPACITOR ELECT 47MF 25V C508 1-131-992-11 s CAP, CERAMIC 100000PF F 1608 C509 1-131-992-11 s CAP, CERAMIC 100000PF F 1608 C510 1-131-992-11 s CAP, CERAMIC 100000PF F 1608 C511 1-128-992-11 s CAPACITOR ELECT 47MF 25V C512 1-131-992-11 s CAP, CERAMIC 100000PF F 1608 C513 1-131-992-11 s CAP, CERAMIC 100000PF F 1608 C514 1-128-992-11 s CAPACITOR ELECT 47MF 25V C515 1-125-827-11 s CAPACITOR,CERAMIC 1MF/25V C516 1-125-827-11 s CAPACITOR,CERAMIC 1MF/25V C518 1-164-943-11 s CAPACITOR,CHIP CERAMIC 0.01MF C520 1-128-992-11 s CAPACITOR ELECT 47MF 25V C522 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C601 1-119-667-11 s CAPACITOR CERAMIC 22MF/10V(F) C602 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C604 1-131-992-11 s CAP, CERAMIC 100000PF F 1608 C606 1-128-992-11 s CAPACITOR ELECT 47MF 25V C607 1-128-992-11 s CAPACITOR ELECT 47MF 25V C608 1-131-992-11 s CAP, CERAMIC 100000PF F 1608 C609 1-131-992-11 s CAP, CERAMIC 100000PF F 1608 C610 1-131-992-11 s CAP, CERAMIC 100000PF F 1608 C611 1-128-992-11 s CAPACITOR ELECT 47MF 25V C612 1-131-992-11 s CAP, CERAMIC 100000PF F 1608 C613 1-125-827-11 s CAPACITOR,CERAMIC 1MF/25V C614 1-131-992-11 s CAP, CERAMIC 100000PF F 1608 C615 1-128-992-11 s CAPACITOR ELECT 47MF 25V C616 1-125-827-11 s CAPACITOR,CERAMIC 1MF/25V C651 1-119-667-11 s CAPACITOR CERAMIC 22MF/10V(F) C652 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C655 1-131-992-11 s CAP, CERAMIC 100000PF F 1608 C656 1-128-992-11 s CAPACITOR ELECT 47MF 25V C657 1-128-992-11 s CAPACITOR ELECT 47MF 25V C658 1-131-992-11 s CAP, CERAMIC 100000PF F 1608 C659 1-131-992-11 s CAP, CERAMIC 100000PF F 1608 C660 1-131-992-11 s CAP, CERAMIC 100000PF F 1608 C661 1-128-992-11 s CAPACITOR ELECT 47MF 25V C662 1-131-992-11 s CAP, CERAMIC 100000PF F 1608 C663 1-131-992-11 s CAP, CERAMIC 100000PF F 1608 C664 1-128-992-11 s CAPACITOR ELECT 47MF 25V C665 1-125-827-11 s CAPACITOR,CERAMIC 1MF/25V C666 1-125-827-11 s CAPACITOR,CERAMIC 1MF/25V C701 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C702 1-126-205-11 s CAPACITOR,ELECT 47MF/6.3 C703 1-164-943-11 s CAPACITOR,CHIP CERAMIC 0.01MF C704 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C705 1-117-720-11 s CAPACITOR, CERAMIC 4.7MF/10V F www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 4-8 VPL-CS7/ES2 (C BOARD ;For VPL-CS7) Ref. No. or Q'ty Part No. SP Description C706 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C707 1-164-943-11 s CAPACITOR,CHIP CERAMIC 0.01MF C708 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C709 1-164-850-11 s CAPACITOR,CHIP CERAMIC 10PF/50 C711 1-164-850-11 s CAPACITOR,CHIP CERAMIC 10PF/50 C712 1-164-943-11 s CAPACITOR,CHIP CERAMIC 0.01MF C713 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C714 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C715 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C716 1-125-837-91 s CAPACITOR,CHIP CERAMIC1MF/6.3V C717 1-164-943-11 s CAPACITOR,CHIP CERAMIC 0.01MF C718 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C719 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C727 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C728 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C729 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C786 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C787 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C801 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C802 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C803 1-126-205-11 s CAPACITOR,ELECT 47MF/6.3 C804 1-126-205-11 s CAPACITOR,ELECT 47MF/6.3 C805 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C806 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C807 1-126-205-11 s CAPACITOR,ELECT 47MF/6.3 C808 1-126-205-11 s CAPACITOR,ELECT 47MF/6.3 C809 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C810 1-126-205-11 s CAPACITOR,ELECT 47MF/6.3 C816 1-126-205-11 s CAPACITOR,ELECT 47MF/6.3 C817 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C818 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C819 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C820 1-128-992-11 s CAPACITOR ELECT 47MF 25V C821 1-128-992-11 s CAPACITOR ELECT 47MF 25V C822 1-128-992-11 s CAPACITOR ELECT 47MF 25V C823 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C824 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C826 1-128-992-11 s CAPACITOR ELECT 47MF 25V C827 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C828 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C829 1-164-943-11 s CAPACITOR,CHIP CERAMIC 0.01MF C830 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C837 1-131-992-11 s CAP, CERAMIC 100000PF F 1608 C838 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C839 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C840 1-131-992-11 s CAP, CERAMIC 100000PF F 1608 C841 1-131-992-11 s CAP, CERAMIC 100000PF F 1608 C842 1-117-370-11 s CAPACITOR CERAMIC 10MF (3216) C843 1-117-370-11 s CAPACITOR CERAMIC 10MF (3216) C844 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C845 1-128-992-11 s CAPACITOR ELECT 47MF 25V C846 1-128-992-11 s CAPACITOR ELECT 47MF 25V C847 1-131-992-11 s CAP, CERAMIC 100000PF F 1608 C849 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C850 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C852 1-131-992-11 s CAP, CERAMIC 100000PF F 1608 C853 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C854 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C855 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V (C BOARD ;For VPL-CS7) Ref. No. or Q'ty Part No. SP Description C856 1-117-370-11 s CAPACITOR CERAMIC 10MF (3216) C857 1-117-370-11 s CAPACITOR CERAMIC 10MF (3216) C858 1-131-992-11 s CAP, CERAMIC 100000PF F 1608 C859 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C860 1-162-637-11 s CAPACITOR,CHIP CERAMIC 0.47MF C861 1-164-882-11 s CAPACITOR,CERAMIC 220PF/16V CH C862 1-131-992-11 s CAP, CERAMIC 100000PF F 1608 C901 1-164-943-11 s CAPACITOR,CHIP CERAMIC 0.01MF C902 1-164-943-11 s CAPACITOR,CHIP CERAMIC 0.01MF C903 1-164-943-11 s CAPACITOR,CHIP CERAMIC 0.01MF C904 1-117-720-11 s CAPACITOR, CERAMIC 4.7MF/10V F C905 1-119-667-11 s CAPACITOR CERAMIC 22MF/10V(F) C906 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C907 1-131-992-11 s CAP, CERAMIC 100000PF F 1608 C911 1-128-992-11 s CAPACITOR ELECT 47MF 25V C914 1-131-992-11 s CAP, CERAMIC 100000PF F 1608 C935 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C947 1-126-205-11 s CAPACITOR,ELECT 47MF/6.3 C948 1-126-205-11 s CAPACITOR,ELECT 47MF/6.3 C949 1-126-205-11 s CAPACITOR,ELECT 47MF/6.3 C953 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C957 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V CN501 1-794-823-11 s CONNECTOR (ZIF), FPC/FFC 32P CN601 1-794-823-11 s CONNECTOR (ZIF), FPC/FFC 32P CN651 1-794-823-11 s CONNECTOR (ZIF), FPC/FFC 32P CN702 1-770-629-21 s PIN, CONNECTOR 12P CN703 1-770-622-21 s PIN, CONNECTOR 5P CN802 1-770-621-21 s PIN, CONNECTOR 4P CN803 1-770-623-21 s PIN, CONNECTOR 6P CN804 1-764-829-11 o CONNECTOR, FPC 24P CN805 1-691-491-21 s CONNECTOR, FFC/FPC 12P CN806 1-580-055-21 o PIN, CONNECTOR 2P CN807 1-770-622-21 s PIN, CONNECTOR 5P CN809 1-580-056-21 s PIN,CONNECTOR 3P CN810 1-580-056-21 o PIN,CONNECTOR 3P CN811 1-580-056-21 o PIN,CONNECTOR 3P CN812 1-580-056-21 s PIN,CONNECTOR 3P CN813 1-770-622-21 s PIN, CONNECTOR 5P CN814 1-580-055-21 o PIN, CONNECTOR 2P CN815 1-580-057-11 s PIN,CONNECTOR 4P CN901 1-784-828-11 s CONNECTOR, D SUB CN902 1-770-860-11 s CONNECTOR, S TERMINAL CN903 1-770-622-21 s PIN, CONNECTOR 5P CN904 1-770-626-21 s PIN, CONNECTOR (L TYPE) 9P D201 8-719-988-61 s DIODE 1SS355TE-17 D202 8-719-988-61 s DIODE 1SS355TE-17 D701 8-719-024-77 s DIODE HN1D03FU-TE85L D709 8-719-036-80 s DIODE RD3.9SB D711 8-719-036-80 s DIODE RD3.9SB D712 8-719-059-53 s DIODE MA3J14700LSO D713 8-719-055-30 s DIODE D1FS4A-TA D714 8-719-055-30 s DIODE D1FS4A-TA D801 8-719-045-53 s DIODE SEC1801C D802 8-719-045-61 s DIODE SEC1901C D803 8-719-045-61 s DIODE SEC1901C D804 8-719-055-30 s DIODE D1FS4A-TA D805 8-719-036-94 s DIODE RD5.6SB-T1 D806 8-719-055-30 s DIODE D1FS4A-TA www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 4-9 VPL-CS7/ES2 (C BOARD ;For VPL-CS7) Ref. No. or Q'ty Part No. SP Description D807 8-719-941-86 s DIODE DAN202U D808 8-719-941-86 s DIODE DAN202U D810 8-719-055-30 s DIODE D1FS4A-TA D811 8-719-055-30 s DIODE D1FS4A-TA D812 8-719-036-94 s DIODE RD5.6SB-T1 D813 8-719-036-94 s DIODE RD5.6SB-T1 D814 8-719-036-94 s DIODE RD5.6SB-T1 D815 8-719-036-94 s DIODE RD5.6SB-T1 D816 8-719-158-37 s DIODE RD9.1SB2 D817 8-719-158-37 s DIODE RD9.1SB2 D818 8-719-059-53 s DIODE MA3J14700LSO D819 8-719-059-53 s DIODE MA3J14700LSO D902 8-719-036-80 s DIODE RD3.9SB D903 8-719-036-94 s DIODE RD5.6SB-T1 D904 8-719-036-94 s DIODE RD5.6SB-T1 D905 8-719-059-53 s DIODE MA3J14700LSO D906 8-719-059-53 s DIODE MA3J14700LSO D907 8-719-059-53 s DIODE MA3J14700LSO D908 8-719-024-77 s DIODE HN1D03FU-TE85L D909 8-719-941-86 s DIODE DAN202U D912 8-719-036-94 s DIODE RD5.6SB-T1 D913 8-719-036-94 s DIODE RD5.6SB-T1 D914 8-719-059-53 s DIODE MA3J14700LSO D915 8-719-059-53 s DIODE MA3J14700LSO D916 8-719-059-53 s DIODE MA3J14700LSO D917 8-719-024-77 s DIODE HN1D03FU-TE85L D918 8-719-036-80 s DIODE RD3.9SB D919 8-719-036-80 s DIODE RD3.9SB D920 8-719-036-80 s DIODE RD3.9SB D921 8-719-036-80 s DIODE RD3.9SB FB101 1-414-921-11 s INDUCTOR, FERRITE BEAD FB102 1-414-921-11 s INDUCTOR, FERRITE BEAD FB103 1-414-921-11 s INDUCTOR, FERRITE BEAD FB105 1-414-921-11 s INDUCTOR, FERRITE BEAD FB106 1-414-921-11 s INDUCTOR, FERRITE BEAD FB301 1-500-451-11 s MICRO INDUCTOR (CHIP) 41P750S FB302 1-414-921-11 s INDUCTOR, FERRITE BEAD FB303 1-414-921-11 s INDUCTOR, FERRITE BEAD FB304 1-414-921-11 s INDUCTOR, FERRITE BEAD FB305 1-414-921-11 s INDUCTOR, FERRITE BEAD FB306 1-414-921-11 s INDUCTOR, FERRITE BEAD FB401 1-500-451-11 s MICRO INDUCTOR (CHIP) 41P750S FB402 1-500-451-11 s MICRO INDUCTOR (CHIP) 41P750S FB501 1-414-921-11 s INDUCTOR, FERRITE BEAD FB601 1-414-921-11 s INDUCTOR, FERRITE BEAD FB651 1-414-921-11 s INDUCTOR, FERRITE BEAD FB801 1-414-921-11 s INDUCTOR, FERRITE BEAD FB802 1-414-921-11 s INDUCTOR, FERRITE BEAD FB803 1-414-921-11 s INDUCTOR, FERRITE BEAD FB804 1-414-921-11 s INDUCTOR, FERRITE BEAD FB805 1-414-921-11 s INDUCTOR, FERRITE BEAD FB806 1-414-921-11 s INDUCTOR, FERRITE BEAD FB807 1-414-921-11 s INDUCTOR, FERRITE BEAD FB808 1-500-451-11 s MICRO INDUCTOR (CHIP) 41P750S FB809 1-500-451-11 s MICRO INDUCTOR (CHIP) 41P750S FB810 1-500-451-11 s MICRO INDUCTOR (CHIP) 41P750S FB811 1-500-451-11 s MICRO INDUCTOR (CHIP) 41P750S FB812 1-500-451-11 s MICRO INDUCTOR (CHIP) 41P750S FB813 1-414-921-11 s INDUCTOR, FERRITE BEAD (C BOARD ;For VPL-CS7) Ref. No. or Q'ty Part No. SP Description FB814 1-414-921-11 s INDUCTOR, FERRITE BEAD FB815 1-414-921-11 s INDUCTOR, FERRITE BEAD FB816 1-414-921-11 s INDUCTOR, FERRITE BEAD FB817 1-414-921-11 s INDUCTOR, FERRITE BEAD FB818 1-414-921-11 s INDUCTOR, FERRITE BEAD FB819 1-414-921-11 s INDUCTOR, FERRITE BEAD FB820 1-414-921-11 s INDUCTOR, FERRITE BEAD FB821 1-414-921-11 s INDUCTOR, FERRITE BEAD FB822 1-414-921-11 s INDUCTOR, FERRITE BEAD FB823 1-414-921-11 s INDUCTOR, FERRITE BEAD FB824 1-414-921-11 s INDUCTOR, FERRITE BEAD FB825 1-414-921-11 s INDUCTOR, FERRITE BEAD FB826 1-414-921-11 s INDUCTOR, FERRITE BEAD FB827 1-414-921-11 s INDUCTOR, FERRITE BEAD FB901 1-414-921-11 s INDUCTOR, FERRITE BEAD FB902 1-218-648-11 s RESISTOR CHIP 15 1/16W(1608) FB903 1-218-648-11 s RESISTOR CHIP 15 1/16W(1608) FB904 1-218-648-11 s RESISTOR CHIP 15 1/16W(1608) IC101 6-704-958-01 s IC AIC1117A-18PYJTR IC102 6-706-128-01 s IC PW2200B-05L IC103 6-703-225-01 s IC S-80928CNMC-G8YT2G IC202 8-759-646-02 s IC M52347FP-TE IC203 8-752-108-35 s IC CXA2171AQ IC204 8-759-548-95 s IC SN74LV00APWR IC205 8-759-549-14 s IC SN74LV244APWR IC302 8-759-475-43 s IC TC74LCX125FT(EL) IC303 6-703-225-01 s IC S-80928CNMC-G8YT2G IC304 6-704-929-01 s IC CY25023SZC-1T IC305 8-759-548-96 s IC SN74LV02APWR IC306 6-804-088-02 s IC MBM29LV800TA-70PFTN751PW115 IC401 8-752-424-18 s IC CXD3536R IC402 8-759-831-52 s IC TC7WH125FK(TE85R) IC403 6-703-225-01 s IC S-80928CNMC-G8YT2G IC404 6-703-225-01 s IC S-80928CNMC-G8YT2G IC407 8-759-679-58 s IC SN74AHCT541PWR IC408 8-759-679-58 s IC SN74AHCT541PWR IC409 8-759-679-58 s IC SN74AHCT541PWR IC410 8-759-490-43 s IC TC74VHCT540AFT(EL) IC501 8-752-110-22 s IC CXA7005R-T4 IC502 8-759-643-48 s IC BA00ASFP-E2 IC503 6-705-025-01 s IC PQ20WZ1UJ00H IC504 8-759-679-05 s IC TC7WH34FU(TE12R) IC601 8-752-110-22 s IC CXA7005R-T4 IC651 8-752-110-22 s IC CXA7005R-T4 IC701 6-704-953-01 s IC AIC1117A-33PYJTR IC703 6-706-022-01 s IC HD64F2378VFQ34V IC704 6-703-225-01 s IC S-80928CNMC-G8YT2G IC705 6-702-688-01 s IC M24C64-WMN6T(B) IC801 6-704-954-01 s IC AIC1117A-50PYJTR IC802 6-702-301-01 s IC TK11125CSCL-G IC803 6-704-954-01 s IC AIC1117A-50PYJTR IC804 6-704-958-01 s IC AIC1117A-18PYJTR IC805 6-704-953-01 s IC AIC1117A-33PYJTR IC806 6-704-952-01 s IC AIC1084-PEJTR IC807 8-759-643-48 s IC BA00ASFP-E2 IC808 8-759-643-48 s IC BA00ASFP-E2 IC809 8-759-643-48 s IC BA00ASFP-E2 IC810 8-759-575-16 s IC LMC7101BIM5X www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 4-10 VPL-CS7/ES2 (C BOARD ;For VPL-CS7) Ref. No. or Q'ty Part No. SP Description IC811 8-759-460-79 s IC BA09FP-E2 IC812 8-759-580-33 s IC BA6288FS-E2 IC813 8-759-831-52 s IC TC7WH125FK(TE85R) IC814 8-759-352-94 s IC TDA7309D013TR IC815 6-702-697-01 s IC TPA2001D1PWR IC901 8-759-661-55 s IC ST24FC21M6TR IC902 8-759-833-99 s IC MC74HC4052ADTR2 IC904 8-759-090-19 s IC SN75453BPS IC920 6-705-902-01 s IC EL5364IUZ-T7 J801 1-566-822-21 s JACK J901 1-785-549-41 o JACK, PIN YELLOW L101 1-469-522-11 s INDUCTOR 1.0UH (NLFV25) L102 1-469-522-11 s INDUCTOR 1.0UH (NLFV25) L103 1-469-522-11 s INDUCTOR 1.0UH (NLFV25) L104 1-469-522-11 s INDUCTOR 1.0UH (NLFV25) L201 1-469-522-11 s INDUCTOR 1.0UH (NLFV25) L401 1-469-522-11 s INDUCTOR 1.0UH (NLFV25) L503 1-469-522-11 s INDUCTOR 1.0UH (NLFV25) L504 1-469-522-11 s INDUCTOR 1.0UH (NLFV25) L603 1-469-522-11 s INDUCTOR 1.0UH (NLFV25) L604 1-469-522-11 s INDUCTOR 1.0UH (NLFV25) L653 1-469-522-11 s INDUCTOR 1.0UH (NLFV25) L654 1-469-522-11 s INDUCTOR 1.0UH (NLFV25) L801 1-469-522-11 s INDUCTOR 1.0UH (NLFV25) L902 1-469-522-11 s INDUCTOR 1.0UH (NLFV25) L905 1-469-522-11 s INDUCTOR 1.0UH (NLFV25) Q201 8-729-905-35 s TRANSISTOR 2SC4081-R Q202 8-729-013-28 s TRANSISTOR HN1B01FU-TE85R Q203 8-729-013-28 s TRANSISTOR HN1B01FU-TE85R Q204 8-729-026-53 s TRANSISTOR 2SA1576A-T106-QR Q205 8-729-907-00 s TRANSISTOR DTC114EU Q206 8-729-026-53 s TRANSISTOR 2SA1576A-T106-QR Q207 8-729-026-53 s TRANSISTOR 2SA1576A-T106-QR Q209 8-729-905-35 s TRANSISTOR 2SC4081-R Q403 8-729-905-35 s TRANSISTOR 2SC4081-R Q404 8-729-013-28 s TRANSISTOR HN1B01FU-TE85R Q501 8-729-013-28 s TRANSISTOR HN1B01FU-TE85R Q502 8-729-013-28 s TRANSISTOR HN1B01FU-TE85R Q601 8-729-013-28 s TRANSISTOR HN1B01FU-TE85R Q602 8-729-013-28 s TRANSISTOR HN1B01FU-TE85R Q651 8-729-013-28 s TRANSISTOR HN1B01FU-TE85R Q652 8-729-013-28 s TRANSISTOR HN1B01FU-TE85R Q701 6-550-014-01 s TRANSISTOR SSM6N15FU(TE85R) Q702 8-729-013-28 s TRANSISTOR HN1B01FU-TE85R Q703 6-550-014-01 s TRANSISTOR SSM6N15FU(TE85R) Q704 6-550-014-01 s TRANSISTOR SSM6N15FU(TE85R) Q801 8-729-905-35 s TRANSISTOR 2SC4081-R Q802 8-729-028-73 s TRANSISTOR DTA114EUA-T106 Q803 8-729-028-73 s TRANSISTOR DTA114EUA-T106 Q804 8-729-028-73 s TRANSISTOR DTA114EUA-T106 Q806 8-729-427-72 s TRANSISTOR XP4501-TXE Q807 8-729-427-72 s TRANSISTOR XP4501-TXE Q808 8-729-026-53 s TRANSISTOR 2SA1576A-T106-QR Q809 8-729-907-00 s TRANSISTOR DTC114EU Q901 8-729-907-00 s TRANSISTOR DTC114EU Q903 8-729-907-00 s TRANSISTOR DTC114EU Q904 8-729-907-00 s TRANSISTOR DTC114EU (C BOARD ;For VPL-CS7) Ref. No. or Q'ty Part No. SP Description R006 1-218-990-11 s RESISTOR,CHIP 0 1/16W (1005) R109 1-218-945-11 s RESISTOR,CHIP 220 1/16W(1005) R110 1-218-945-11 s RESISTOR,CHIP 220 1/16W(1005) R111 1-218-945-11 s RESISTOR,CHIP 220 1/16W(1005) R112 1-218-945-11 s RESISTOR,CHIP 220 1/16W(1005) R113 1-218-945-11 s RESISTOR,CHIP 220 1/16W(1005) R114 1-218-945-11 s RESISTOR,CHIP 220 1/16W(1005) R115 1-208-695-11 s RESISTOR CHIP 3.3K 1/16W(1005) R119 1-218-990-11 s RESISTOR,CHIP 0 1/16W (1005) R120 1-218-990-11 s RESISTOR,CHIP 0 1/16W (1005) R121 1-218-990-11 s RESISTOR,CHIP 0 1/16W (1005) R126 1-218-990-11 s RESISTOR,CHIP 0 1/16W (1005) R127 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R129 1-218-990-11 s RESISTOR,CHIP 0 1/16W (1005) R130 1-218-989-11 s RESISTOR,CHIP 1M 1/16W (1005) R132 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R133 1-218-953-11 s RESISTOR, CHIP 1K 1/16W R138 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R145 1-218-941-81 s RESISTOR,CHIP 100,1/16W (1005) R146 1-218-941-81 s RESISTOR,CHIP 100,1/16W (1005) R147 1-218-941-81 s RESISTOR,CHIP 100,1/16W (1005) R149 1-218-941-81 s RESISTOR,CHIP 100,1/16W (1005) R150 1-218-937-11 s RESISTOR, CHIP 47 R151 1-218-937-11 s RESISTOR, CHIP 47 R158 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R159 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R169 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R170 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R171 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R172 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R173 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R174 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R175 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R176 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R177 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R179 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R203 1-208-635-11 s RESISTOR CHIP 10 1/16W (1005) R204 1-208-635-11 s RESISTOR CHIP 10 1/16W (1005) R205 1-218-953-11 s RESISTOR, CHIP 1K 1/16W R206 1-218-961-11 s RESISTOR, CHIP 4.7K 1/16W R207 1-218-937-11 s RESISTOR, CHIP 47 R208 1-218-973-11 s RESISTOR,CHIP 47K 1/16W (1005) R209 1-218-973-11 s RESISTOR,CHIP 47K 1/16W (1005) R210 1-208-635-11 s RESISTOR CHIP 10 1/16W (1005) R211 1-218-953-11 s RESISTOR, CHIP 1K 1/16W R212 1-218-953-11 s RESISTOR, CHIP 1K 1/16W R213 1-218-953-11 s RESISTOR, CHIP 1K 1/16W R214 1-218-953-11 s RESISTOR, CHIP 1K 1/16W R222 1-218-973-11 s RESISTOR,CHIP 47K 1/16W (1005) R223 1-218-973-11 s RESISTOR,CHIP 47K 1/16W (1005) R228 1-219-601-11 s RES, METAL FILM CHIP 62K(1005) R229 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R230 1-218-961-11 s RESISTOR, CHIP 4.7K 1/16W R231 1-218-973-11 s RESISTOR,CHIP 47K 1/16W (1005) R232 1-218-973-11 s RESISTOR,CHIP 47K 1/16W (1005) R234 1-218-941-81 s RESISTOR,CHIP 100,1/16W (1005) R235 1-218-941-81 s RESISTOR,CHIP 100,1/16W (1005) R236 1-218-990-11 s RESISTOR,CHIP 0 1/16W (1005) R237 1-218-961-11 s RESISTOR, CHIP 4.7K 1/16W www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 4-11 VPL-CS7/ES2 (C BOARD ;For VPL-CS7) Ref. No. or Q'ty Part No. SP Description R241 1-218-973-11 s RESISTOR,CHIP 47K 1/16W (1005) R243 1-218-990-11 s RESISTOR,CHIP 0 1/16W (1005) R244 1-208-695-11 s RESISTOR CHIP 3.3K 1/16W(1005) R245 1-218-990-11 s RESISTOR,CHIP 0 1/16W (1005) R246 1-218-945-11 s RESISTOR,CHIP 220 1/16W(1005) R247 1-218-957-11 s RESISTOR,CHIP 2.2K 1/16W(1608) R248 1-218-937-11 s RESISTOR, CHIP 47 R249 1-218-937-11 s RESISTOR, CHIP 47 R250 1-218-937-11 s RESISTOR, CHIP 47 R251 1-208-707-11 s RESISTOR,CHIP 10K 1/16W (1005) R254 1-218-937-11 s RESISTOR, CHIP 47 R255 1-218-937-11 s RESISTOR, CHIP 47 R256 1-208-683-11 s RESISTOR CHIP 1K 1/16W (1005) R257 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R262 1-208-947-11 s RESISTOR CHIP 330K 1/16W(1005) R263 1-218-937-11 s RESISTOR, CHIP 47 R264 1-218-937-11 s RESISTOR, CHIP 47 R266 1-218-990-11 s RESISTOR,CHIP 0 1/16W (1005) R271 1-218-949-11 s RESISTOR,CHIP 470 1/16W R272 1-218-949-11 s RESISTOR,CHIP 470 1/16W R307 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R310 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R312 1-218-953-11 s RESISTOR, CHIP 1K 1/16W R314 1-218-953-11 s RESISTOR, CHIP 1K 1/16W R315 1-218-941-81 s RESISTOR,CHIP 100,1/16W (1005) R316 1-218-961-11 s RESISTOR, CHIP 4.7K 1/16W R317 1-218-941-81 s RESISTOR,CHIP 100,1/16W (1005) R318 1-218-961-11 s RESISTOR, CHIP 4.7K 1/16W R325 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R327 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R328 1-208-643-11 s RESISTOR CHIP 22 1/16W (1005) R330 1-218-990-11 s RESISTOR,CHIP 0 1/16W (1005) R333 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R337 1-218-990-11 s RESISTOR,CHIP 0 1/16W (1005) R339 1-218-990-11 s RESISTOR,CHIP 0 1/16W (1005) R341 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R344 1-218-957-11 s RESISTOR,CHIP 2.2K 1/16W(1608) R345 1-208-643-11 s RESISTOR CHIP 22 1/16W (1005) R346 1-208-643-11 s RESISTOR CHIP 22 1/16W (1005) R347 1-208-643-11 s RESISTOR CHIP 22 1/16W (1005) R349 1-218-990-11 s RESISTOR,CHIP 0 1/16W (1005) R350 1-218-990-11 s RESISTOR,CHIP 0 1/16W (1005) R354 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R356 1-218-990-11 s RESISTOR,CHIP 0 1/16W (1005) R360 1-216-815-11 s RESISTOR,CHIP 330 1/10W 1608 R401 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R402 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R403 1-218-937-11 s RESISTOR, CHIP 47 R404 1-218-937-11 s RESISTOR, CHIP 47 R414 1-208-643-11 s RESISTOR CHIP 22 1/16W (1005) R416 1-208-643-11 s RESISTOR CHIP 22 1/16W (1005) R422 1-218-937-11 s RESISTOR, CHIP 47 R423 1-218-937-11 s RESISTOR, CHIP 47 R424 1-218-937-11 s RESISTOR, CHIP 47 R428 1-218-941-81 s RESISTOR,CHIP 100,1/16W (1005) R429 1-218-957-11 s RESISTOR,CHIP 2.2K 1/16W(1608) R430 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R432 1-218-961-11 s RESISTOR, CHIP 4.7K 1/16W R433 1-218-953-11 s RESISTOR, CHIP 1K 1/16W (C BOARD ;For VPL-CS7) Ref. No. or Q'ty Part No. SP Description R434 1-218-973-11 s RESISTOR,CHIP 47K 1/16W (1005) R435 1-218-961-11 s RESISTOR, CHIP 4.7K 1/16W R436 1-218-961-11 s RESISTOR, CHIP 4.7K 1/16W R437 1-218-953-11 s RESISTOR, CHIP 1K 1/16W R440 1-218-961-11 s RESISTOR, CHIP 4.7K 1/16W R441 1-218-961-11 s RESISTOR, CHIP 4.7K 1/16W R443 1-218-937-11 s RESISTOR, CHIP 47 R444 1-218-937-11 s RESISTOR, CHIP 47 R447 1-218-990-11 s RESISTOR,CHIP 0 1/16W (1005) R502 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R503 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R504 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R505 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R506 1-218-941-81 s RESISTOR,CHIP 100,1/16W (1005) R507 1-218-957-11 s RESISTOR,CHIP 2.2K 1/16W(1608) R508 1-218-957-11 s RESISTOR,CHIP 2.2K 1/16W(1608) R509 1-208-635-11 s RESISTOR CHIP 10 1/16W (1005) R510 1-208-635-11 s RESISTOR CHIP 10 1/16W (1005) R512 1-218-937-11 s RESISTOR, CHIP 47 R514 1-218-973-11 s RESISTOR,CHIP 47K 1/16W (1005) R515 1-218-961-11 s RESISTOR, CHIP 4.7K 1/16W R516 1-208-683-11 s RESISTOR CHIP 1K 1/16W (1005) R517 1-208-699-11 s RESISTOR,CHIP 4.7K 1/16W(1005) R601 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R602 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R604 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R605 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R606 1-218-941-81 s RESISTOR,CHIP 100,1/16W (1005) R607 1-218-957-11 s RESISTOR,CHIP 2.2K 1/16W(1608) R608 1-218-957-11 s RESISTOR,CHIP 2.2K 1/16W(1608) R609 1-208-635-11 s RESISTOR CHIP 10 1/16W (1005) R610 1-208-635-11 s RESISTOR CHIP 10 1/16W (1005) R612 1-218-937-11 s RESISTOR, CHIP 47 R652 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R653 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R655 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R656 1-218-941-81 s RESISTOR,CHIP 100,1/16W (1005) R657 1-218-957-11 s RESISTOR,CHIP 2.2K 1/16W(1608) R658 1-218-957-11 s RESISTOR,CHIP 2.2K 1/16W(1608) R659 1-208-635-11 s RESISTOR CHIP 10 1/16W (1005) R660 1-208-635-11 s RESISTOR CHIP 10 1/16W (1005) R662 1-218-937-11 s RESISTOR, CHIP 47 R702 1-218-937-11 s RESISTOR, CHIP 47 R703 1-218-990-11 s RESISTOR,CHIP 0 1/16W (1005) R704 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R705 1-218-941-81 s RESISTOR,CHIP 100,1/16W (1005) R706 1-208-699-11 s RESISTOR,CHIP 4.7K 1/16W(1005) R707 1-218-959-11 s RESISTOR, CHIP 3.3K R708 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R709 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R710 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R711 1-218-961-11 s RESISTOR, CHIP 4.7K 1/16W R712 1-218-961-11 s RESISTOR, CHIP 4.7K 1/16W R714 1-218-990-11 s RESISTOR,CHIP 0 1/16W (1005) R715 1-218-990-11 s RESISTOR,CHIP 0 1/16W (1005) R716 1-218-973-11 s RESISTOR,CHIP 47K 1/16W (1005) R717 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R718 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R719 1-218-957-11 s RESISTOR,CHIP 2.2K 1/16W(1608) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 4-12 VPL-CS7/ES2 (C BOARD ;For VPL-CS7) Ref. No. or Q'ty Part No. SP Description R720 1-218-957-11 s RESISTOR,CHIP 2.2K 1/16W(1608) R721 1-218-957-11 s RESISTOR,CHIP 2.2K 1/16W(1608) R722 1-218-957-11 s RESISTOR,CHIP 2.2K 1/16W(1608) R723 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R725 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R726 1-208-635-11 s RESISTOR CHIP 10 1/16W (1005) R727 1-218-945-11 s RESISTOR,CHIP 220 1/16W(1005) R729 1-218-973-11 s RESISTOR,CHIP 47K 1/16W (1005) R730 1-218-953-11 s RESISTOR, CHIP 1K 1/16W R732 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R733 1-218-973-11 s RESISTOR,CHIP 47K 1/16W (1005) R734 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R735 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R736 1-218-953-11 s RESISTOR, CHIP 1K 1/16W R737 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R739 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R741 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R742 1-218-937-11 s RESISTOR, CHIP 47 R743 1-218-937-11 s RESISTOR, CHIP 47 R744 1-218-971-11 s RESISTOR,CHIP 33K 1/16W (1005) R745 1-218-971-11 s RESISTOR,CHIP 33K 1/16W (1005) R748 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R749 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R750 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R751 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R752 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R753 1-218-990-11 s RESISTOR,CHIP 0 1/16W (1005) R756 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R757 1-218-953-11 s RESISTOR, CHIP 1K 1/16W R758 1-218-953-11 s RESISTOR, CHIP 1K 1/16W R759 1-218-941-81 s RESISTOR,CHIP 100,1/16W (1005) R760 1-218-941-81 s RESISTOR,CHIP 100,1/16W (1005) R761 1-218-941-81 s RESISTOR,CHIP 100,1/16W (1005) R762 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R763 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R767 1-218-990-11 s RESISTOR,CHIP 0 1/16W (1005) R768 1-218-990-11 s RESISTOR,CHIP 0 1/16W (1005) R773 1-218-941-81 s RESISTOR,CHIP 100,1/16W (1005) R774 1-218-941-81 s RESISTOR,CHIP 100,1/16W (1005) R776 1-218-941-81 s RESISTOR,CHIP 100,1/16W (1005) R778 1-218-961-11 s RESISTOR, CHIP 4.7K 1/16W R779 1-218-961-11 s RESISTOR, CHIP 4.7K 1/16W R782 1-218-941-81 s RESISTOR,CHIP 100,1/16W (1005) R783 1-218-941-81 s RESISTOR,CHIP 100,1/16W (1005) R784 1-218-941-81 s RESISTOR,CHIP 100,1/16W (1005) R785 1-208-699-11 s RESISTOR,CHIP 4.7K 1/16W(1005) R801 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R802 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R803 1-218-953-11 s RESISTOR, CHIP 1K 1/16W R804 1-218-953-11 s RESISTOR, CHIP 1K 1/16W R805 1-218-945-11 s RESISTOR,CHIP 220 1/16W(1005) R806 1-218-941-81 s RESISTOR,CHIP 100,1/16W (1005) R807 1-218-941-81 s RESISTOR,CHIP 100,1/16W (1005) R808 1-218-941-81 s RESISTOR,CHIP 100,1/16W (1005) R814 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R815 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R816 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R817 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R818 1-218-965-11 s RESISTOR, CHIP 10K 1/16W (C BOARD ;For VPL-CS7) Ref. No. or Q'ty Part No. SP Description R819 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R820 1-208-707-11 s RESISTOR,CHIP 10K 1/16W (1005) R826 1-218-953-11 s RESISTOR, CHIP 1K 1/16W R827 1-218-971-11 s RESISTOR,CHIP 33K 1/16W (1005) R828 1-218-949-11 s RESISTOR,CHIP 470 1/16W R829 1-218-961-11 s RESISTOR, CHIP 4.7K 1/16W R830 1-218-971-11 s RESISTOR,CHIP 33K 1/16W (1005) R831 1-218-949-11 s RESISTOR,CHIP 470 1/16W R832 1-218-961-11 s RESISTOR, CHIP 4.7K 1/16W R833 1-218-971-11 s RESISTOR,CHIP 33K 1/16W (1005) R834 1-218-949-11 s RESISTOR,CHIP 470 1/16W R835 1-218-961-11 s RESISTOR, CHIP 4.7K 1/16W R836 1-218-941-81 s RESISTOR,CHIP 100,1/16W (1005) R837 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R839 1-218-969-11 s RESISTOR,CHIP 22K 1/16W (1608) R840 1-218-969-11 s RESISTOR,CHIP 22K 1/16W (1608) R841 1-218-969-11 s RESISTOR,CHIP 22K 1/16W (1608) R842 1-218-969-11 s RESISTOR,CHIP 22K 1/16W (1608) R843 1-218-973-11 s RESISTOR,CHIP 47K 1/16W (1005) R846 1-218-969-11 s RESISTOR,CHIP 22K 1/16W (1608) R847 1-218-947-11 s RESISTOR, CHIP 330 1/16W R848 1-218-947-11 s RESISTOR, CHIP 330 1/16W R849 1-218-949-11 s RESISTOR,CHIP 470 1/16W R850 1-218-945-11 s RESISTOR,CHIP 220 1/16W(1005) R851 1-218-945-11 s RESISTOR,CHIP 220 1/16W(1005) R852 1-218-957-11 s RESISTOR,CHIP 2.2K 1/16W(1608) R853 1-218-957-11 s RESISTOR,CHIP 2.2K 1/16W(1608) R854 1-218-957-11 s RESISTOR,CHIP 2.2K 1/16W(1608) R855 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R856 1-218-985-11 s RESISTOR CHIP 470K 1/16W(1005) R857 1-218-985-11 s RESISTOR CHIP 470K 1/16W(1005) R858 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R859 1-218-941-81 s RESISTOR,CHIP 100,1/16W (1005) R860 1-218-941-81 s RESISTOR,CHIP 100,1/16W (1005) R861 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R862 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R863 1-218-977-11 s RESISTOR,CHIP 100K 1/16W(1005) R864 1-218-973-11 s RESISTOR,CHIP 47K 1/16W (1005) R865 1-218-973-11 s RESISTOR,CHIP 47K 1/16W (1005) R866 1-218-941-81 s RESISTOR,CHIP 100,1/16W (1005) R867 1-218-941-81 s RESISTOR,CHIP 100,1/16W (1005) R868 1-218-977-11 s RESISTOR,CHIP 100K 1/16W(1005) R869 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R871 1-218-978-11 s RESISTOR,CHIP 120K 1/16W(1005) R901 1-218-973-11 s RESISTOR,CHIP 47K 1/16W (1005) R902 1-218-973-11 s RESISTOR,CHIP 47K 1/16W (1005) R903 1-218-973-11 s RESISTOR,CHIP 47K 1/16W (1005) R904 1-218-951-11 s RESISTOR, CHIP 680 1/16 R905 1-218-951-11 s RESISTOR, CHIP 680 1/16 R906 1-218-990-11 s RESISTOR,CHIP 0 1/16W (1005) R907 1-218-990-11 s RESISTOR,CHIP 0 1/16W (1005) R908 1-216-811-11 s RESISTOR, CHIP 150 1/16W(1608) R909 1-216-811-11 s RESISTOR, CHIP 150 1/16W(1608) R910 1-216-811-11 s RESISTOR, CHIP 150 1/16W(1608) R911 1-218-953-11 s RESISTOR, CHIP 1K 1/16W R912 1-218-937-11 s RESISTOR, CHIP 47 R913 1-216-811-11 s RESISTOR, CHIP 150 1/16W(1608) R914 1-216-811-11 s RESISTOR, CHIP 150 1/16W(1608) R915 1-216-811-11 s RESISTOR, CHIP 150 1/16W(1608) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 4-13 VPL-CS7/ES2 (C BOARD ;For VPL-CS7) Ref. No. or Q'ty Part No. SP Description R916 1-218-953-11 s RESISTOR, CHIP 1K 1/16W R917 1-216-811-11 s RESISTOR, CHIP 150 1/16W(1608) R918 1-216-811-11 s RESISTOR, CHIP 150 1/16W(1608) R919 1-216-811-11 s RESISTOR, CHIP 150 1/16W(1608) R920 1-218-937-11 s RESISTOR, CHIP 47 R921 1-218-941-81 s RESISTOR,CHIP 100,1/16W (1005) R922 1-218-941-81 s RESISTOR,CHIP 100,1/16W (1005) R923 1-218-941-81 s RESISTOR,CHIP 100,1/16W (1005) R924 1-218-945-11 s RESISTOR,CHIP 220 1/16W(1005) R925 1-216-864-11 s CONDUCTOR, CHIP (1608) R926 1-216-864-11 s CONDUCTOR, CHIP (1608) R927 1-216-864-11 s CONDUCTOR, CHIP (1608) R928 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R929 1-218-973-11 s RESISTOR,CHIP 47K 1/16W (1005) R930 1-218-973-11 s RESISTOR,CHIP 47K 1/16W (1005) R931 1-218-973-11 s RESISTOR,CHIP 47K 1/16W (1005) R932 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R933 1-218-990-11 s RESISTOR,CHIP 0 1/16W (1005) R934 1-218-990-11 s RESISTOR,CHIP 0 1/16W (1005) R935 1-218-937-11 s RESISTOR, CHIP 47 R936 1-218-937-11 s RESISTOR, CHIP 47 R937 1-218-937-11 s RESISTOR, CHIP 47 R938 1-218-937-11 s RESISTOR, CHIP 47 R941 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R942 1-218-990-11 s RESISTOR,CHIP 0 1/16W (1005) R943 1-218-990-11 s RESISTOR,CHIP 0 1/16W (1005) R944 1-218-990-11 s RESISTOR,CHIP 0 1/16W (1005) R948 1-218-951-11 s RESISTOR, CHIP 680 1/16 R949 1-218-951-11 s RESISTOR, CHIP 680 1/16 R954 1-218-951-11 s RESISTOR, CHIP 680 1/16 R959 1-218-951-11 s RESISTOR, CHIP 680 1/16 R963 1-216-811-11 s RESISTOR, CHIP 150 1/16W(1608) R964 1-216-815-11 s RESISTOR,CHIP 330 1/10W 1608 R965 1-216-811-11 s RESISTOR, CHIP 150 1/16W(1608) R966 1-216-811-11 s RESISTOR, CHIP 150 1/16W(1608) R967 1-216-815-11 s RESISTOR,CHIP 330 1/10W 1608 R968 1-216-815-11 s RESISTOR,CHIP 330 1/10W 1608 R969 1-216-811-11 s RESISTOR, CHIP 150 1/16W(1608) R970 1-216-811-11 s RESISTOR, CHIP 150 1/16W(1608) R971 1-218-953-11 s RESISTOR, CHIP 1K 1/16W R975 1-218-937-11 s RESISTOR, CHIP 47 R976 1-218-937-11 s RESISTOR, CHIP 47 R978 1-216-815-11 s RESISTOR,CHIP 330 1/10W 1608 R979 1-216-811-11 s RESISTOR, CHIP 150 1/16W(1608) R986 1-218-937-11 s RESISTOR, CHIP 47 R987 1-218-937-11 s RESISTOR, CHIP 47 R988 1-218-937-11 s RESISTOR, CHIP 47 R993 1-208-643-11 s RESISTOR CHIP 22 1/16W (1005) R994 1-208-643-11 s RESISTOR CHIP 22 1/16W (1005) R995 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R998 1-218-977-11 s RESISTOR,CHIP 100K 1/16W(1005) RB102 1-234-372-11 s RES, NETWORK 100X4 (1005) RB108 1-234-372-11 s RES, NETWORK 100X4 (1005) RB109 1-234-372-11 s RES, NETWORK 100X4 (1005) RB110 1-234-372-11 s RES, NETWORK 100X4 (1005) RB111 1-234-372-11 s RES, NETWORK 100X4 (1005) RB112 1-234-372-11 s RES, NETWORK 100X4 (1005) RB401 1-234-370-11 s RES, NETWORK 22X4 (1005) (C BOARD ;For VPL-CS7) Ref. No. or Q'ty Part No. SP Description RB402 1-234-370-11 s RES, NETWORK 22X4 (1005) RB403 1-234-370-11 s RES, NETWORK 22X4 (1005) RB404 1-234-370-11 s RES, NETWORK 22X4 (1005) RB405 1-234-370-11 s RES, NETWORK 22X4 (1005) RB406 1-234-370-11 s RES, NETWORK 22X4 (1005) RB407 1-234-371-11 s RES, NETWORK 47X4 (1005) RB408 1-234-371-11 s RES, NETWORK 47X4 (1005) RB409 1-234-371-11 s RES, NETWORK 47X4 (1005) RB410 1-234-371-11 s RES, NETWORK 47X4 (1005) RB411 1-234-371-11 s RES, NETWORK 47X4 (1005) RB412 1-234-371-11 s RES, NETWORK 47X4 (1005) RB413 1-234-371-11 s RES, NETWORK 47X4 (1005) RB414 1-234-371-11 s RES, NETWORK 47X4 (1005) RB415 1-234-370-11 s RES, NETWORK 22X4 (1005) RB501 1-234-370-11 s RES, NETWORK 22X4 (1005) RB601 1-234-370-11 s RES, NETWORK 22X4 (1005) RB651 1-234-370-11 s RES, NETWORK 22X4 (1005) RB701 1-234-372-11 s RES, NETWORK 100X4 (1005) RB705 1-234-372-11 s RES, NETWORK 100X4 (1005) RB707 1-234-372-11 s RES, NETWORK 100X4 (1005) TH702 1-803-382-11 s THERMISTOR (10K) TH801 1-803-615-11 s THERMISTOR, POSITIVE X101 1-795-756-11 s VIBRATOR, CRYSTAL X201 1-813-124-21 s VIBRATOR, CERAMIC X301 1-813-326-21 s VIBRATOR, CRYSTAL X302 1-813-326-21 s VIBRATOR, CRYSTAL X701 1-813-326-21 s VIBRATOR, CRYSTAL www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 4-14 VPL-CS7/ES2 -------------------- C BOARD ;For VPL-ES2 -------------------- Ref. No. or Q'ty Part No. SP Description 1pc A-1067-062-A s MOUNTED CIRCUIT BOARD, C C101 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C102 1-127-715-11 s CAPACITOR,CERAMIC 0.22MF B1608 C103 1-127-715-11 s CAPACITOR,CERAMIC 0.22MF B1608 C104 1-127-715-11 s CAPACITOR,CERAMIC 0.22MF B1608 C105 1-126-205-11 s CAPACITOR,ELECT 47MF/6.3 C106 1-126-205-11 s CAPACITOR,ELECT 47MF/6.3 C107 1-126-205-11 s CAPACITOR,ELECT 47MF/6.3 C108 1-126-205-11 s CAPACITOR,ELECT 47MF/6.3 C109 1-119-923-11 s CAPACITOR,CHIP CERAMIC 0.047MF C110 1-164-937-11 s CAPACITOR,CHIP CERAMIC 1000PF C111 1-135-995-91 s CAP,CHIP CERAMIC39000PF B 1608 C112 1-117-446-11 s CAPACITOR CERAMIC 3900PF 16V C113 1-119-923-11 s CAPACITOR,CHIP CERAMIC 0.047MF C114 1-119-923-11 s CAPACITOR,CHIP CERAMIC 0.047MF C115 1-126-205-11 s CAPACITOR,ELECT 47M/6.3 C116 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C117 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C118 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C119 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C120 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C121 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C123 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C125 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C126 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C127 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C128 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C129 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C130 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C131 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C132 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C133 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C134 1-126-205-11 s CAPACITOR,ELECT 47MF/6.3 C136 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C137 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C138 1-126-205-11 s CAPACITOR,ELECT 47MF/6.3 C139 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C140 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C141 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C142 1-164-854-11 s CAPACITOR,CHIP CERAMIC 15PF/50 C143 1-164-854-11 s CAPACITOR,CHIP CERAMIC 15PF/50 C144 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C145 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C146 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C147 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C148 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C149 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C150 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C151 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C152 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C153 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C154 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C155 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C156 1-126-205-11 s CAPACITOR,ELECT 47MF/6.3 C157 1-126-205-11 s CAPACITOR,ELECT 47MF/6.3 C158 1-126-205-11 s CAPACITOR,ELECT 47MF/6.3 C201 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C205 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V (C BOARD ;For VPL-ES2) Ref. No. or Q'ty Part No. SP Description C206 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C207 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C208 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C209 1-117-720-11 s CAPACITOR, CERAMIC 4.7MF/10V F C210 1-164-937-11 s CAPACITOR,CHIP CERAMIC 1000PF C211 1-125-891-11 s CAPACITOR CERAMIC 0.47MF/10V C212 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C215 1-137-987-81 s CAP,CHIP CERAMIC 0.068MF C216 1-117-720-11 s CAPACITOR, CERAMIC 4.7MF/10V F C217 1-117-720-11 s CAPACITOR, CERAMIC 4.7MF/10V F C218 1-117-370-11 s CAPACITOR CERAMIC 10MF (3216) C220 1-127-715-11 s CAPACITOR,CERAMIC 0.22MF B1608 C221 1-125-837-91 s CAPACITOR,CHIP CERAMIC1MF/6.3V C222 1-125-837-91 s CAPACITOR,CHIP CERAMIC1MF/6.3V C223 1-127-715-11 s CAPACITOR,CERAMIC 0.22MF B1608 C224 1-125-891-11 s CAPACITOR CERAMIC 0.47MF/10V C225 1-164-943-11 s CAPACITOR,CHIP CERAMIC 0.01MF C227 1-164-874-11 s CAPACITOR,CHIP CERAMIC 100PF C228 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C229 1-164-882-11 s CAPACITOR,CERAMIC 220PF/16V CH C230 1-119-667-11 s CAPACITOR CERAMIC 22MF/10V(F) C231 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C232 1-125-837-91 s CAPACITOR,CHIP CERAMIC1MF/6.3V C233 1-164-943-11 s CAPACITOR,CHIP CERAMIC 0.01MF C234 1-164-943-11 s CAPACITOR,CHIP CERAMIC 0.01MF C236 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C237 1-107-826-11 s CAPACITOR,CHIP CERAMIC 0.1MF C238 1-125-837-91 s CAPACITOR,CHIP CERAMIC1MF/6.3V C239 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C242 1-117-720-11 s CAPACITOR, CERAMIC 4.7MF/10V F C243 1-117-720-11 s CAPACITOR, CERAMIC 4.7MF/10V F C301 1-119-667-11 s CAPACITOR CERAMIC 22MF/10V(F) C302 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C304 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C306 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C308 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C310 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C311 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C312 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C314 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C316 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C317 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C318 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C319 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C321 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C322 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C324 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C325 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C326 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C327 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C332 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C337 1-119-667-11 s CAPACITOR CERAMIC 22MF/10V(F) C339 1-164-852-11 s CAPACITOR,CHIP CERAMIC 12PF/50 C340 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C341 1-164-852-11 s CAPACITOR,CHIP CERAMIC 12PF/50 C342 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C343 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C344 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C345 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 4-15 VPL-CS7/ES2 (C BOARD ;For VPL-ES2) Ref. No. or Q'ty Part No. SP Description C347 1-119-667-11 s CAPACITOR CERAMIC 22MF/10V(F) C348 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C349 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C350 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C351 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C352 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C353 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C354 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C355 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C356 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C357 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C358 1-119-667-11 s CAPACITOR CERAMIC 22MF/10V(F) C359 1-119-667-11 s CAPACITOR CERAMIC 22MF/10V(F) C361 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C363 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C364 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C365 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C367 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C368 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C369 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C370 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C371 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C372 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C373 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C379 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C380 1-164-852-11 s CAPACITOR,CHIP CERAMIC 12PF/50 C381 1-164-852-11 s CAPACITOR,CHIP CERAMIC 12PF/50 C401 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C402 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C403 1-117-370-11 s CAPACITOR CERAMIC 10MF (3216) C404 1-164-943-11 s CAPACITOR,CHIP CERAMIC 0.01MF C405 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C406 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C407 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C408 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C409 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C410 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C411 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C412 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C413 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C414 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C415 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C416 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C417 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C418 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C419 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C420 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C421 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C422 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C423 1-117-370-11 s CAPACITOR CERAMIC 10MF (3216) C426 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C427 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C428 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C429 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C430 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C431 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C432 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C433 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C435 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V (C BOARD ;For VPL-ES2) Ref. No. or Q'ty Part No. SP Description C436 1-126-205-11 s CAPACITOR,ELECT 47M/6.3 C437 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C438 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C439 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C441 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C442 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C443 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C444 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C445 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C501 1-119-667-11 s CAPACITOR CERAMIC 22MF/10V(F) C502 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C503 1-128-992-11 s CAPACITOR ELECT 47MF 25V C504 1-131-992-11 s CAP, CERAMIC 100000PF F 1608 C506 1-128-992-11 s CAPACITOR ELECT 47MF 25V C507 1-128-992-11 s CAPACITOR ELECT 47MF 25V C508 1-131-992-11 s CAP, CERAMIC 100000PF F 1608 C509 1-131-992-11 s CAP, CERAMIC 100000PF F 1608 C510 1-131-992-11 s CAP, CERAMIC 100000PF F 1608 C511 1-128-992-11 s CAPACITOR ELECT 47MF 25V C512 1-131-992-11 s CAP, CERAMIC 100000PF F 1608 C513 1-131-992-11 s CAP, CERAMIC 100000PF F 1608 C514 1-128-992-11 s CAPACITOR ELECT 47MF 25V C515 1-125-827-11 s CAPACITOR,CERAMIC 1MF/25V C516 1-125-827-11 s CAPACITOR,CERAMIC 1MF/25V C518 1-164-943-11 s CAPACITOR,CHIP CERAMIC 0.01MF C520 1-128-992-11 s CAPACITOR ELECT 47MF 25V C522 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C601 1-119-667-11 s CAPACITOR CERAMIC 22MF/10V(F) C602 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C604 1-131-992-11 s CAP, CERAMIC 100000PF F 1608 C606 1-128-992-11 s CAPACITOR ELECT 47MF 25V C607 1-128-992-11 s CAPACITOR ELECT 47MF 25V C608 1-131-992-11 s CAP, CERAMIC 100000PF F 1608 C609 1-131-992-11 s CAP, CERAMIC 100000PF F 1608 C610 1-131-992-11 s CAP, CERAMIC 100000PF F 1608 C611 1-128-992-11 s CAPACITOR ELECT 47MF 25V C612 1-131-992-11 s CAP, CERAMIC 100000PF F 1608 C613 1-125-827-11 s CAPACITOR,CERAMIC 1MF/25V C614 1-131-992-11 s CAP, CERAMIC 100000PF F 1608 C615 1-128-992-11 s CAPACITOR ELECT 47MF 25V C616 1-125-827-11 s CAPACITOR,CERAMIC 1MF/25V C651 1-119-667-11 s CAPACITOR CERAMIC 22MF/10V(F) C652 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C655 1-131-992-11 s CAP, CERAMIC 100000PF F 1608 C656 1-128-992-11 s CAPACITOR ELECT 47MF 25V C657 1-128-992-11 s CAPACITOR ELECT 47MF 25V C658 1-131-992-11 s CAP, CERAMIC 100000PF F 1608 C659 1-131-992-11 s CAP, CERAMIC 100000PF F 1608 C660 1-131-992-11 s CAP, CERAMIC 100000PF F 1608 C661 1-128-992-11 s CAPACITOR ELECT 47MF 25V C662 1-131-992-11 s CAP, CERAMIC 100000PF F 1608 C663 1-131-992-11 s CAP, CERAMIC 100000PF F 1608 C664 1-128-992-11 s CAPACITOR ELECT 47MF 25V C665 1-125-827-11 s CAPACITOR,CERAMIC 1MF/25V C666 1-125-827-11 s CAPACITOR,CERAMIC 1MF/25V C701 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C702 1-126-205-11 s CAPACITOR,ELECT 47M/6.3 C703 1-164-943-11 s CAPACITOR,CHIP CERAMIC 0.01MF C704 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 4-16 VPL-CS7/ES2 (C BOARD ;For VPL-ES2) Ref. No. or Q'ty Part No. SP Description C705 1-117-720-11 s CAPACITOR, CERAMIC 4.7MF/10V F C706 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C707 1-164-943-11 s CAPACITOR,CHIP CERAMIC 0.01MF C708 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C709 1-164-850-11 s CAPACITOR,CHIP CERAMIC 10PF/50 C711 1-164-850-11 s CAPACITOR,CHIP CERAMIC 10PF/50 C712 1-164-943-11 s CAPACITOR,CHIP CERAMIC 0.01MF C713 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C714 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C715 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C716 1-125-837-91 s CAPACITOR,CHIP CERAMIC1MF/6.3V C717 1-164-943-11 s CAPACITOR,CHIP CERAMIC 0.01MF C718 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C719 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C727 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C728 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C729 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C786 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C787 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C801 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C802 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C803 1-126-205-11 s CAPACITOR,ELECT 47MF/6.3 C804 1-126-205-11 s CAPACITOR,ELECT 47MF/6.3 C805 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C806 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C807 1-126-205-11 s CAPACITOR,ELECT 47MF/6.3 C808 1-126-205-11 s CAPACITOR,ELECT 47MF/6.3 C809 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C810 1-126-205-11 s CAPACITOR,ELECT 47MF/6.3 C816 1-126-205-11 s CAPACITOR,ELECT 47MF/6.3 C817 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C818 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C819 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C820 1-128-992-11 s CAPACITOR ELECT 47MF 25V C821 1-128-992-11 s CAPACITOR ELECT 47MF 25V C822 1-128-992-11 s CAPACITOR ELECT 47MF 25V C823 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C824 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C826 1-128-992-11 s CAPACITOR ELECT 47MF 25V C827 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C828 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C829 1-164-943-11 s CAPACITOR,CHIP CERAMIC 0.01MF C830 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C837 1-131-992-11 s CAP, CERAMIC 100000PF F 1608 C838 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C839 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C840 1-131-992-11 s CAP, CERAMIC 100000PF F 1608 C841 1-131-992-11 s CAP, CERAMIC 100000PF F 1608 C842 1-117-370-11 s CAPACITOR CERAMIC 10MF (3216) C843 1-117-370-11 s CAPACITOR CERAMIC 10MF (3216) C844 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C845 1-128-992-11 s CAPACITOR ELECT 47MF 25V C846 1-128-992-11 s CAPACITOR ELECT 47MF 25V C847 1-131-992-11 s CAP, CERAMIC 100000PF F 1608 C849 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C850 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C852 1-131-992-11 s CAP, CERAMIC 100000PF F 1608 C853 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C854 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V (C BOARD ;For VPL-ES2) Ref. No. or Q'ty Part No. SP Description C855 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C856 1-117-370-11 s CAPACITOR CERAMIC 10MF (3216) C857 1-117-370-11 s CAPACITOR CERAMIC 10MF (3216) C858 1-131-992-11 s CAP, CERAMIC 100000PF F 1608 C859 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C860 1-162-637-11 s CAPACITOR,CHIP CERAMIC 0.47MF C861 1-164-882-11 s CAPACITOR,CERAMIC 220PF/16V CH C862 1-131-992-11 s CAP, CERAMIC 100000PF F 1608 C901 1-164-943-11 s CAPACITOR,CHIP CERAMIC 0.01MF C902 1-164-943-11 s CAPACITOR,CHIP CERAMIC 0.01MF C903 1-164-943-11 s CAPACITOR,CHIP CERAMIC 0.01MF C904 1-117-720-11 s CAPACITOR, CERAMIC 4.7MF/10V F C905 1-119-667-11 s CAPACITOR CERAMIC 22MF/10V(F) C906 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C907 1-131-992-11 s CAP, CERAMIC 100000PF F 1608 C911 1-128-992-11 s CAPACITOR ELECT 47MF 25V C914 1-131-992-11 s CAP, CERAMIC 100000PF F 1608 C935 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C947 1-126-205-11 s CAPACITOR,ELECT 47MF/6.3 C948 1-126-205-11 s CAPACITOR,ELECT 47MF/6.3 C949 1-126-205-11 s CAPACITOR,ELECT 47MF/6.3 C956 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V C957 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V CN501 1-794-823-11 s CONNECTOR (ZIF), FPC/FFC 32P CN601 1-794-823-11 s CONNECTOR (ZIF), FPC/FFC 32P CN651 1-794-823-11 s CONNECTOR (ZIF), FPC/FFC 32P CN702 1-770-629-21 s PIN, CONNECTOR 12P CN703 1-770-622-21 s PIN, CONNECTOR 5P CN802 1-770-621-21 s PIN, CONNECTOR 4P CN803 1-770-623-21 s PIN, CONNECTOR 6P CN804 1-764-829-11 o CONNECTOR, FPC 24P CN805 1-691-491-21 s CONNECTOR, FFC/FPC 12P CN806 1-580-055-21 o PIN, CONNECTOR 2P CN807 1-770-622-21 s PIN, CONNECTOR 5P CN809 1-580-056-21 s PIN,CONNECTOR 3P CN810 1-580-056-21 o PIN,CONNECTOR 3P CN811 1-580-056-21 o PIN,CONNECTOR 3P CN812 1-580-056-21 s PIN,CONNECTOR 3P CN813 1-770-622-21 s PIN, CONNECTOR 5P CN814 1-580-055-21 o PIN, CONNECTOR 2P CN815 1-580-057-11 s PIN,CONNECTOR 4P CN901 1-784-828-11 s CONNECTOR, D SUB CN902 1-770-860-11 s CONNECTOR, S TERMINAL CN903 1-770-622-21 s PIN, CONNECTOR 5P CN904 1-770-626-21 s PIN, CONNECTOR (L TYPE) 9P D201 8-719-988-61 s DIODE 1SS355TE-17 D202 8-719-988-61 s DIODE 1SS355TE-17 D701 8-719-024-77 s DIODE HN1D03FU-TE85L D709 8-719-036-80 s DIODE RD3.9SB D711 8-719-036-80 s DIODE RD3.9SB D712 8-719-059-53 s DIODE MA3J14700LSO D713 8-719-055-30 s DIODE D1FS4A-TA D714 8-719-055-30 s DIODE D1FS4A-TA D801 8-719-045-53 s DIODE SEC1801C D802 8-719-045-61 s DIODE SEC1901C D803 8-719-045-61 s DIODE SEC1901C D804 8-719-055-30 s DIODE D1FS4A-TA D805 8-719-036-94 s DIODE RD5.6SB-T1 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 4-17 VPL-CS7/ES2 (C BOARD ;For VPL-ES2) Ref. No. or Q'ty Part No. SP Description D806 8-719-055-30 s DIODE D1FS4A-TA D807 8-719-941-86 s DIODE DAN202U D808 8-719-941-86 s DIODE DAN202U D810 8-719-055-30 s DIODE D1FS4A-TA D811 8-719-055-30 s DIODE D1FS4A-TA D812 8-719-036-94 s DIODE RD5.6SB-T1 D813 8-719-036-94 s DIODE RD5.6SB-T1 D814 8-719-036-94 s DIODE RD5.6SB-T1 D815 8-719-036-94 s DIODE RD5.6SB-T1 D816 8-719-158-37 s DIODE RD9.1SB2 D817 8-719-158-37 s DIODE RD9.1SB2 D818 8-719-059-53 s DIODE MA3J14700LSO D819 8-719-059-53 s DIODE MA3J14700LSO D902 8-719-036-80 s DIODE RD3.9SB D903 8-719-036-94 s DIODE RD5.6SB-T1 D904 8-719-036-94 s DIODE RD5.6SB-T1 D905 8-719-059-53 s DIODE MA3J14700LSO D906 8-719-059-53 s DIODE MA3J14700LSO D907 8-719-059-53 s DIODE MA3J14700LSO D908 8-719-024-77 s DIODE HN1D03FU-TE85L D909 8-719-941-86 s DIODE DAN202U D912 8-719-036-94 s DIODE RD5.6SB-T1 D913 8-719-036-94 s DIODE RD5.6SB-T1 D914 8-719-059-53 s DIODE MA3J14700LSO D915 8-719-059-53 s DIODE MA3J14700LSO D916 8-719-059-53 s DIODE MA3J14700LSO D918 8-719-036-80 s DIODE RD3.9SB D919 8-719-036-80 s DIODE RD3.9SB D920 8-719-036-80 s DIODE RD3.9SB D921 8-719-036-80 s DIODE RD3.9SB FB101 1-414-921-11 s INDUCTOR, FERRITE BEAD FB102 1-414-921-11 s INDUCTOR, FERRITE BEAD FB103 1-414-921-11 s INDUCTOR, FERRITE BEAD FB105 1-414-921-11 s INDUCTOR, FERRITE BEAD FB106 1-414-921-11 s INDUCTOR, FERRITE BEAD FB301 1-500-451-11 s MICRO INDUCTOR (CHIP) 41P750S FB302 1-414-921-11 s INDUCTOR, FERRITE BEAD FB303 1-414-921-11 s INDUCTOR, FERRITE BEAD FB304 1-414-921-11 s INDUCTOR, FERRITE BEAD FB305 1-414-921-11 s INDUCTOR, FERRITE BEAD FB306 1-414-921-11 s INDUCTOR, FERRITE BEAD FB401 1-500-451-11 s MICRO INDUCTOR (CHIP) 41P750S FB402 1-500-451-11 s MICRO INDUCTOR (CHIP) 41P750S FB501 1-414-921-11 s INDUCTOR, FERRITE BEAD FB601 1-414-921-11 s INDUCTOR, FERRITE BEAD FB651 1-414-921-11 s INDUCTOR, FERRITE BEAD FB801 1-414-921-11 s INDUCTOR, FERRITE BEAD FB802 1-414-921-11 s INDUCTOR, FERRITE BEAD FB803 1-414-921-11 s INDUCTOR, FERRITE BEAD FB804 1-414-921-11 s INDUCTOR, FERRITE BEAD FB805 1-414-921-11 s INDUCTOR, FERRITE BEAD FB806 1-414-921-11 s INDUCTOR, FERRITE BEAD FB807 1-414-921-11 s INDUCTOR, FERRITE BEAD FB808 1-500-451-11 s MICRO INDUCTOR (CHIP) 41P750S FB809 1-500-451-11 s MICRO INDUCTOR (CHIP) 41P750S FB810 1-500-451-11 s MICRO INDUCTOR (CHIP) 41P750S FB811 1-500-451-11 s MICRO INDUCTOR (CHIP) 41P750S FB812 1-500-451-11 s MICRO INDUCTOR (CHIP) 41P750S FB813 1-414-921-11 s INDUCTOR, FERRITE BEAD (C BOARD ;For VPL-ES2) Ref. No. or Q'ty Part No. SP Description FB814 1-414-921-11 s INDUCTOR, FERRITE BEAD FB815 1-414-921-11 s INDUCTOR, FERRITE BEAD FB816 1-414-921-11 s INDUCTOR, FERRITE BEAD FB817 1-414-921-11 s INDUCTOR, FERRITE BEAD FB818 1-414-921-11 s INDUCTOR, FERRITE BEAD FB819 1-414-921-11 s INDUCTOR, FERRITE BEAD FB820 1-414-921-11 s INDUCTOR, FERRITE BEAD FB821 1-414-921-11 s INDUCTOR, FERRITE BEAD FB822 1-414-921-11 s INDUCTOR, FERRITE BEAD FB823 1-414-921-11 s INDUCTOR, FERRITE BEAD FB824 1-414-921-11 s INDUCTOR, FERRITE BEAD FB825 1-414-921-11 s INDUCTOR, FERRITE BEAD FB826 1-414-921-11 s INDUCTOR, FERRITE BEAD FB827 1-414-921-11 s INDUCTOR, FERRITE BEAD FB901 1-414-921-11 s INDUCTOR, FERRITE BEAD FB902 1-218-648-11 s RESISTOR CHIP 15 1/16W(1608) FB903 1-218-648-11 s RESISTOR CHIP 15 1/16W(1608) FB904 1-218-648-11 s RESISTOR CHIP 15 1/16W(1608) IC101 6-704-958-01 s IC AIC1117A-18PYJTR IC102 6-706-128-01 s IC PW2200B-05L IC103 6-703-225-01 s IC S-80928CNMC-G8YT2G IC202 8-759-646-02 s IC M52347FP-TE IC203 8-752-108-35 s IC CXA2171AQ IC204 8-759-548-95 s IC SN74LV00APWR IC205 8-759-549-14 s IC SN74LV244APWR IC302 8-759-475-43 s IC TC74LCX125FT(EL) IC303 6-703-225-01 s IC S-80928CNMC-G8YT2G IC304 6-704-929-01 s IC CY25023SZC-1T IC305 8-759-548-96 s IC SN74LV02APWR IC306 6-804-088-02 s IC MBM29LV800TA-70PFTN751PW115 IC401 8-752-424-18 s IC CXD3536R IC402 8-759-831-52 s IC TC7WH125FK(TE85R) IC403 6-703-225-01 s IC S-80928CNMC-G8YT2G IC404 6-703-225-01 s IC S-80928CNMC-G8YT2G IC407 8-759-679-58 s IC SN74AHCT541PWR IC408 8-759-679-58 s IC SN74AHCT541PWR IC409 8-759-679-58 s IC SN74AHCT541PWR IC410 8-759-490-43 s IC TC74VHCT540AFT(EL) IC501 8-752-110-22 s IC CXA7005R-T4 IC502 8-759-643-48 s IC BA00ASFP-E2 IC503 6-705-025-01 s IC PQ20WZ1UJ00H IC504 8-759-679-05 s IC TC7WH34FU(TE12R) IC601 8-752-110-22 s IC CXA7005R-T4 IC651 8-752-110-22 s IC CXA7005R-T4 IC701 6-704-953-01 s IC AIC1117A-33PYJTR IC703 6-706-022-01 s IC HD64F2378VFQ34V IC704 6-703-225-01 s IC S-80928CNMC-G8YT2G IC705 6-702-688-01 s IC M24C64-WMN6T(B) IC801 6-704-954-01 s IC AIC1117A-50PYJTR IC802 6-702-301-01 s IC TK11125CSCL-G IC803 6-704-954-01 s IC AIC1117A-50PYJTR IC804 6-704-958-01 s IC AIC1117A-18PYJTR IC805 6-704-953-01 s IC AIC1117A-33PYJTR IC806 6-704-952-01 s IC AIC1084-PEJTR IC807 8-759-643-48 s IC BA00ASFP-E2 IC808 8-759-643-48 s IC BA00ASFP-E2 IC809 8-759-643-48 s IC BA00ASFP-E2 IC810 8-759-575-16 s IC LMC7101BIM5X www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 4-18 VPL-CS7/ES2 (C BOARD ;For VPL-ES2) Ref. No. or Q'ty Part No. SP Description IC811 8-759-460-79 s IC BA09FP-E2 IC812 8-759-580-33 s IC BA6288FS-E2 IC813 8-759-831-52 s IC TC7WH125FK(TE85R) IC814 8-759-352-94 s IC TDA7309D013TR IC815 6-702-697-01 s IC TPA2001D1PWR IC901 8-759-661-55 s IC ST24FC21M6TR IC902 8-759-833-99 s IC MC74HC4052ADTR2 IC919 6-705-902-01 s IC EL5364IUZ-T7 IC920 6-705-902-01 s IC EL5364IUZ-T7 J801 1-566-822-21 s JACK J901 1-785-549-41 o JACK, PIN YELLOW L101 1-469-522-11 s INDUCTOR 1.0UH (NLFV25) L102 1-469-522-11 s INDUCTOR 1.0UH (NLFV25) L103 1-469-522-11 s INDUCTOR 1.0UH (NLFV25) L104 1-469-522-11 s INDUCTOR 1.0UH (NLFV25) L201 1-469-522-11 s INDUCTOR 1.0UH (NLFV25) L401 1-469-522-11 s INDUCTOR 1.0UH (NLFV25) L503 1-469-522-11 s INDUCTOR 1.0UH (NLFV25) L504 1-469-522-11 s INDUCTOR 1.0UH (NLFV25) L603 1-469-522-11 s INDUCTOR 1.0UH (NLFV25) L604 1-469-522-11 s INDUCTOR 1.0UH (NLFV25) L653 1-469-522-11 s INDUCTOR 1.0UH (NLFV25) L654 1-469-522-11 s INDUCTOR 1.0UH (NLFV25) L801 1-469-522-11 s INDUCTOR 1.0UH (NLFV25) L902 1-469-522-11 s INDUCTOR 1.0UH (NLFV25) L904 1-469-522-11 s INDUCTOR 1.0UH (NLFV25) L905 1-469-522-11 s INDUCTOR 1.0UH (NLFV25) Q201 8-729-905-35 s TRANSISTOR 2SC4081-R Q202 8-729-013-28 s TRANSISTOR HN1B01FU-TE85R Q203 8-729-013-28 s TRANSISTOR HN1B01FU-TE85R Q204 8-729-026-53 s TRANSISTOR 2SA1576A-T106-QR Q205 8-729-907-00 s TRANSISTOR DTC114EU Q206 8-729-026-53 s TRANSISTOR 2SA1576A-T106-QR Q207 8-729-026-53 s TRANSISTOR 2SA1576A-T106-QR Q209 8-729-905-35 s TRANSISTOR 2SC4081-R Q403 8-729-905-35 s TRANSISTOR 2SC4081-R Q404 8-729-013-28 s TRANSISTOR HN1B01FU-TE85R Q501 8-729-013-28 s TRANSISTOR HN1B01FU-TE85R Q502 8-729-013-28 s TRANSISTOR HN1B01FU-TE85R Q601 8-729-013-28 s TRANSISTOR HN1B01FU-TE85R Q602 8-729-013-28 s TRANSISTOR HN1B01FU-TE85R Q651 8-729-013-28 s TRANSISTOR HN1B01FU-TE85R Q652 8-729-013-28 s TRANSISTOR HN1B01FU-TE85R Q701 6-550-014-01 s TRANSISTOR SSM6N15FU(TE85R) Q702 8-729-013-28 s TRANSISTOR HN1B01FU-TE85R Q703 6-550-014-01 s TRANSISTOR SSM6N15FU(TE85R) Q704 6-550-014-01 s TRANSISTOR SSM6N15FU(TE85R) Q801 8-729-905-35 s TRANSISTOR 2SC4081-R Q802 8-729-028-73 s TRANSISTOR DTA114EUA-T106 Q803 8-729-028-73 s TRANSISTOR DTA114EUA-T106 Q804 8-729-028-73 s TRANSISTOR DTA114EUA-T106 Q806 8-729-427-72 s TRANSISTOR XP4501-TXE Q807 8-729-427-72 s TRANSISTOR XP4501-TXE Q808 8-729-026-53 s TRANSISTOR 2SA1576A-T106-QR Q809 8-729-907-00 s TRANSISTOR DTC114EU Q901 8-729-907-00 s TRANSISTOR DTC114EU Q903 8-729-907-00 s TRANSISTOR DTC114EU (C BOARD ;For VPL-ES2) Ref. No. or Q'ty Part No. SP Description Q904 8-729-907-00 s TRANSISTOR DTC114EU Q905 8-729-907-00 s TRANSISTOR DTC114EU R001 1-218-990-11 s RESISTOR,CHIP 0 1/16W (1005) R002 1-218-990-11 s RESISTOR,CHIP 0 1/16W (1005) R003 1-218-990-11 s RESISTOR,CHIP 0 1/16W (1005) R004 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R005 1-218-990-11 s RESISTOR,CHIP 0 1/16W (1005) R109 1-218-945-11 s RESISTOR,CHIP 220 1/16W(1005) R110 1-218-945-11 s RESISTOR,CHIP 220 1/16W(1005) R111 1-218-945-11 s RESISTOR,CHIP 220 1/16W(1005) R112 1-218-945-11 s RESISTOR,CHIP 220 1/16W(1005) R113 1-218-945-11 s RESISTOR,CHIP 220 1/16W(1005) R114 1-218-945-11 s RESISTOR,CHIP 220 1/16W(1005) R115 1-208-695-11 s RESISTOR CHIP 3.3K 1/16W(1005) R119 1-218-990-11 s RESISTOR,CHIP 0 1/16W (1005) R120 1-218-990-11 s RESISTOR,CHIP 0 1/16W (1005) R121 1-218-990-11 s RESISTOR,CHIP 0 1/16W (1005) R126 1-218-990-11 s RESISTOR,CHIP 0 1/16W (1005) R127 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R129 1-218-990-11 s RESISTOR,CHIP 0 1/16W (1005) R130 1-218-989-11 s RESISTOR,CHIP 1M 1/16W (1005) R132 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R133 1-218-953-11 s RESISTOR, CHIP 1K 1/16W R138 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R145 1-218-941-81 s RESISTOR,CHIP 100,1/16W (1005) R146 1-218-941-81 s RESISTOR,CHIP 100,1/16W (1005) R147 1-218-941-81 s RESISTOR,CHIP 100,1/16W (1005) R149 1-218-941-81 s RESISTOR,CHIP 100,1/16W (1005) R150 1-218-937-11 s RESISTOR, CHIP 47 R151 1-218-937-11 s RESISTOR, CHIP 47 R158 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R159 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R169 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R170 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R171 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R172 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R173 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R174 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R175 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R176 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R177 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R179 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R203 1-208-635-11 s RESISTOR CHIP 10 1/16W (1005) R204 1-208-635-11 s RESISTOR CHIP 10 1/16W (1005) R205 1-218-953-11 s RESISTOR, CHIP 1K 1/16W R206 1-218-961-11 s RESISTOR, CHIP 4.7K 1/16W R207 1-218-937-11 s RESISTOR, CHIP 47 R208 1-218-973-11 s RESISTOR,CHIP 47K 1/16W (1005) R209 1-218-973-11 s RESISTOR,CHIP 47K 1/16W (1005) R210 1-208-635-11 s RESISTOR CHIP 10 1/16W (1005) R211 1-218-953-11 s RESISTOR, CHIP 1K 1/16W R212 1-218-953-11 s RESISTOR, CHIP 1K 1/16W R213 1-218-953-11 s RESISTOR, CHIP 1K 1/16W R214 1-218-953-11 s RESISTOR, CHIP 1K 1/16W R216 1-218-990-11 s RESISTOR,CHIP 0 1/16W (1005) R217 1-218-990-11 s RESISTOR,CHIP 0 1/16W (1005) R222 1-218-973-11 s RESISTOR,CHIP 47K 1/16W (1005) R223 1-218-973-11 s RESISTOR,CHIP 47K 1/16W (1005) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 4-19 VPL-CS7/ES2 (C BOARD ;For VPL-ES2) Ref. No. or Q'ty Part No. SP Description R228 1-219-601-11 s RES, METAL FILM CHIP 62K(1005) R229 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R230 1-218-961-11 s RESISTOR, CHIP 4.7K 1/16W R231 1-218-973-11 s RESISTOR,CHIP 47K 1/16W (1005) R232 1-218-973-11 s RESISTOR,CHIP 47K 1/16W (1005) R234 1-218-941-81 s RESISTOR,CHIP 100,1/16W (1005) R235 1-218-941-81 s RESISTOR,CHIP 100,1/16W (1005) R236 1-218-990-11 s RESISTOR,CHIP 0 1/16W (1005) R237 1-218-961-11 s RESISTOR, CHIP 4.7K 1/16W R241 1-218-973-11 s RESISTOR,CHIP 47K 1/16W (1005) R243 1-218-990-11 s RESISTOR,CHIP 0 1/16W (1005) R244 1-208-695-11 s RESISTOR CHIP 3.3K 1/16W(1005) R245 1-218-990-11 s RESISTOR,CHIP 0 1/16W (1005) R246 1-218-945-11 s RESISTOR,CHIP 220 1/16W(1005) R247 1-218-957-11 s RESISTOR,CHIP 2.2K 1/16W(1608) R248 1-218-937-11 s RESISTOR, CHIP 47 R249 1-218-937-11 s RESISTOR, CHIP 47 R250 1-218-937-11 s RESISTOR, CHIP 47 R251 1-208-707-11 s RESISTOR,CHIP 10K 1/16W (1005) R254 1-218-937-11 s RESISTOR, CHIP 47 R255 1-218-937-11 s RESISTOR, CHIP 47 R256 1-208-683-11 s RESISTOR CHIP 1K 1/16W (1005) R257 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R262 1-208-947-11 s RESISTOR CHIP 330K 1/16W(1005) R263 1-218-937-11 s RESISTOR, CHIP 47 R264 1-218-937-11 s RESISTOR, CHIP 47 R266 1-218-990-11 s RESISTOR,CHIP 0 1/16W (1005) R271 1-218-949-11 s RESISTOR,CHIP 470 1/16W R272 1-218-949-11 s RESISTOR,CHIP 470 1/16W R307 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R310 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R312 1-218-953-11 s RESISTOR, CHIP 1K 1/16W R314 1-218-953-11 s RESISTOR, CHIP 1K 1/16W R315 1-218-941-81 s RESISTOR,CHIP 100,1/16W (1005) R316 1-218-961-11 s RESISTOR, CHIP 4.7K 1/16W R317 1-218-941-81 s RESISTOR,CHIP 100,1/16W (1005) R318 1-218-961-11 s RESISTOR, CHIP 4.7K 1/16W R325 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R327 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R328 1-208-643-11 s RESISTOR CHIP 22 1/16W (1005) R330 1-218-990-11 s RESISTOR,CHIP 0 1/16W (1005) R333 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R337 1-218-990-11 s RESISTOR,CHIP 0 1/16W (1005) R339 1-218-990-11 s RESISTOR,CHIP 0 1/16W (1005) R341 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R344 1-218-957-11 s RESISTOR,CHIP 2.2K 1/16W(1608) R345 1-208-643-11 s RESISTOR CHIP 22 1/16W (1005) R346 1-208-643-11 s RESISTOR CHIP 22 1/16W (1005) R347 1-208-643-11 s RESISTOR CHIP 22 1/16W (1005) R349 1-218-990-11 s RESISTOR,CHIP 0 1/16W (1005) R350 1-218-990-11 s RESISTOR,CHIP 0 1/16W (1005) R354 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R356 1-218-990-11 s RESISTOR,CHIP 0 1/16W (1005) R360 1-216-815-11 s RESISTOR,CHIP 330 1/10W 1608 R401 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R402 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R403 1-218-937-11 s RESISTOR, CHIP 47 R404 1-218-937-11 s RESISTOR, CHIP 47 R414 1-208-643-11 s RESISTOR CHIP 22 1/16W (1005) (C BOARD ;For VPL-ES2) Ref. No. or Q'ty Part No. SP Description R416 1-208-643-11 s RESISTOR CHIP 22 1/16W (1005) R422 1-218-937-11 s RESISTOR, CHIP 47 R423 1-218-937-11 s RESISTOR, CHIP 47 R424 1-218-937-11 s RESISTOR, CHIP 47 R428 1-218-941-81 s RESISTOR,CHIP 100,1/16W (1005) R429 1-218-957-11 s RESISTOR,CHIP 2.2K 1/16W(1608) R430 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R432 1-218-961-11 s RESISTOR, CHIP 4.7K 1/16W R433 1-218-953-11 s RESISTOR, CHIP 1K 1/16W R434 1-218-973-11 s RESISTOR,CHIP 47K 1/16W (1005) R435 1-218-961-11 s RESISTOR, CHIP 4.7K 1/16W R436 1-218-961-11 s RESISTOR, CHIP 4.7K 1/16W R437 1-218-953-11 s RESISTOR, CHIP 1K 1/16W R440 1-218-961-11 s RESISTOR, CHIP 4.7K 1/16W R441 1-218-961-11 s RESISTOR, CHIP 4.7K 1/16W R443 1-218-937-11 s RESISTOR, CHIP 47 R444 1-218-937-11 s RESISTOR, CHIP 47 R447 1-218-990-11 s RESISTOR,CHIP 0 1/16W (1005) R502 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R503 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R504 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R505 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R506 1-218-941-81 s RESISTOR,CHIP 100,1/16W (1005) R507 1-218-957-11 s RESISTOR,CHIP 2.2K 1/16W(1608) R508 1-218-957-11 s RESISTOR,CHIP 2.2K 1/16W(1608) R509 1-208-635-11 s RESISTOR CHIP 10 1/16W (1005) R510 1-208-635-11 s RESISTOR CHIP 10 1/16W (1005) R512 1-218-937-11 s RESISTOR, CHIP 47 R514 1-218-973-11 s RESISTOR,CHIP 47K 1/16W (1005) R515 1-218-961-11 s RESISTOR, CHIP 4.7K 1/16W R516 1-208-683-11 s RESISTOR CHIP 1K 1/16W (1005) R517 1-208-699-11 s RESISTOR,CHIP 4.7K 1/16W(1005) R601 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R602 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R604 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R605 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R606 1-218-941-81 s RESISTOR,CHIP 100,1/16W (1005) R607 1-218-957-11 s RESISTOR,CHIP 2.2K 1/16W(1608) R608 1-218-957-11 s RESISTOR,CHIP 2.2K 1/16W(1608) R609 1-208-635-11 s RESISTOR CHIP 10 1/16W (1005) R610 1-208-635-11 s RESISTOR CHIP 10 1/16W (1005) R612 1-218-937-11 s RESISTOR, CHIP 47 R652 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R653 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R655 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R656 1-218-941-81 s RESISTOR,CHIP 100,1/16W (1005) R657 1-218-957-11 s RESISTOR,CHIP 2.2K 1/16W(1608) R658 1-218-957-11 s RESISTOR,CHIP 2.2K 1/16W(1608) R659 1-208-635-11 s RESISTOR CHIP 10 1/16W (1005) R660 1-208-635-11 s RESISTOR CHIP 10 1/16W (1005) R662 1-218-937-11 s RESISTOR, CHIP 47 R702 1-218-937-11 s RESISTOR, CHIP 47 R703 1-218-990-11 s RESISTOR,CHIP 0 1/16W (1005) R705 1-218-941-81 s RESISTOR,CHIP 100,1/16W (1005) R706 1-208-699-11 s RESISTOR,CHIP 4.7K 1/16W(1005) R707 1-218-959-11 s RESISTOR, CHIP 3.3K R709 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R710 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R711 1-218-961-11 s RESISTOR, CHIP 4.7K 1/16W www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 4-20 VPL-CS7/ES2 (C BOARD ;For VPL-ES2) Ref. No. or Q'ty Part No. SP Description R712 1-218-961-11 s RESISTOR, CHIP 4.7K 1/16W R714 1-218-990-11 s RESISTOR,CHIP 0 1/16W (1005) R715 1-218-990-11 s RESISTOR,CHIP 0 1/16W (1005) R716 1-218-973-11 s RESISTOR,CHIP 47K 1/16W (1005) R717 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R718 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R719 1-218-957-11 s RESISTOR,CHIP 2.2K 1/16W(1608) R720 1-218-957-11 s RESISTOR,CHIP 2.2K 1/16W(1608) R721 1-218-957-11 s RESISTOR,CHIP 2.2K 1/16W(1608) R722 1-218-957-11 s RESISTOR,CHIP 2.2K 1/16W(1608) R723 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R724 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R725 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R726 1-208-635-11 s RESISTOR CHIP 10 1/16W (1005) R727 1-218-945-11 s RESISTOR,CHIP 220 1/16W(1005) R728 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R729 1-218-973-11 s RESISTOR,CHIP 47K 1/16W (1005) R730 1-218-953-11 s RESISTOR, CHIP 1K 1/16W R732 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R733 1-218-973-11 s RESISTOR,CHIP 47K 1/16W (1005) R734 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R735 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R736 1-218-953-11 s RESISTOR, CHIP 1K 1/16W R737 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R739 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R741 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R742 1-218-937-11 s RESISTOR, CHIP 47 R743 1-218-937-11 s RESISTOR, CHIP 47 R744 1-218-971-11 s RESISTOR,CHIP 33K 1/16W (1005) R745 1-218-971-11 s RESISTOR,CHIP 33K 1/16W (1005) R748 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R749 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R750 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R751 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R752 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R753 1-218-990-11 s RESISTOR,CHIP 0 1/16W (1005) R756 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R757 1-218-953-11 s RESISTOR, CHIP 1K 1/16W R758 1-218-953-11 s RESISTOR, CHIP 1K 1/16W R759 1-218-941-81 s RESISTOR,CHIP 100,1/16W (1005) R760 1-218-941-81 s RESISTOR,CHIP 100,1/16W (1005) R761 1-218-941-81 s RESISTOR,CHIP 100,1/16W (1005) R762 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R763 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R767 1-218-990-11 s RESISTOR,CHIP 0 1/16W (1005) R768 1-218-990-11 s RESISTOR,CHIP 0 1/16W (1005) R773 1-218-941-81 s RESISTOR,CHIP 100,1/16W (1005) R774 1-218-941-81 s RESISTOR,CHIP 100,1/16W (1005) R776 1-218-941-81 s RESISTOR,CHIP 100,1/16W (1005) R778 1-218-961-11 s RESISTOR, CHIP 4.7K 1/16W R779 1-218-961-11 s RESISTOR, CHIP 4.7K 1/16W R782 1-218-941-81 s RESISTOR,CHIP 100,1/16W (1005) R783 1-218-941-81 s RESISTOR,CHIP 100,1/16W (1005) R784 1-218-941-81 s RESISTOR,CHIP 100,1/16W (1005) R785 1-208-699-11 s RESISTOR,CHIP 4.7K 1/16W(1005) R801 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R802 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R803 1-218-953-11 s RESISTOR, CHIP 1K 1/16W R804 1-218-953-11 s RESISTOR, CHIP 1K 1/16W (C BOARD ;For VPL-ES2) Ref. No. or Q'ty Part No. SP Description R805 1-218-945-11 s RESISTOR,CHIP 220 1/16W(1005) R806 1-218-941-81 s RESISTOR,CHIP 100,1/16W (1005) R807 1-218-941-81 s RESISTOR,CHIP 100,1/16W (1005) R808 1-218-941-81 s RESISTOR,CHIP 100,1/16W (1005) R814 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R815 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R816 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R817 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R818 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R819 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R820 1-208-707-11 s RESISTOR,CHIP 10K 1/16W (1005) R826 1-218-953-11 s RESISTOR, CHIP 1K 1/16W R827 1-218-971-11 s RESISTOR,CHIP 33K 1/16W (1005) R828 1-218-949-11 s RESISTOR,CHIP 470 1/16W R829 1-218-961-11 s RESISTOR, CHIP 4.7K 1/16W R830 1-218-971-11 s RESISTOR,CHIP 33K 1/16W (1005) R831 1-218-949-11 s RESISTOR,CHIP 470 1/16W R832 1-218-961-11 s RESISTOR, CHIP 4.7K 1/16W R833 1-218-971-11 s RESISTOR,CHIP 33K 1/16W (1005) R834 1-218-949-11 s RESISTOR,CHIP 470 1/16W R835 1-218-961-11 s RESISTOR, CHIP 4.7K 1/16W R836 1-218-941-81 s RESISTOR,CHIP 100,1/16W (1005) R837 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R839 1-218-969-11 s RESISTOR,CHIP 22K 1/16W (1608) R840 1-218-969-11 s RESISTOR,CHIP 22K 1/16W (1608) R841 1-218-969-11 s RESISTOR,CHIP 22K 1/16W (1608) R842 1-218-969-11 s RESISTOR,CHIP 22K 1/16W (1608) R843 1-218-973-11 s RESISTOR,CHIP 47K 1/16W (1005) R846 1-218-969-11 s RESISTOR,CHIP 22K 1/16W (1608) R847 1-218-947-11 s RESISTOR, CHIP 330 1/16W R848 1-218-947-11 s RESISTOR, CHIP 330 1/16W R849 1-218-949-11 s RESISTOR,CHIP 470 1/16W R850 1-218-945-11 s RESISTOR,CHIP 220 1/16W(1005) R851 1-218-945-11 s RESISTOR,CHIP 220 1/16W(1005) R852 1-218-957-11 s RESISTOR,CHIP 2.2K 1/16W(1608) R853 1-218-957-11 s RESISTOR,CHIP 2.2K 1/16W(1608) R854 1-218-957-11 s RESISTOR,CHIP 2.2K 1/16W(1608) R855 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R856 1-218-985-11 s RESISTOR CHIP 470K 1/16W(1005) R857 1-218-985-11 s RESISTOR CHIP 470K 1/16W(1005) R858 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R859 1-218-941-81 s RESISTOR,CHIP 100,1/16W (1005) R860 1-218-941-81 s RESISTOR,CHIP 100,1/16W (1005) R861 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R862 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R863 1-218-977-11 s RESISTOR,CHIP 100K 1/16W(1005) R864 1-218-973-11 s RESISTOR,CHIP 47K 1/16W (1005) R865 1-218-973-11 s RESISTOR,CHIP 47K 1/16W (1005) R866 1-218-941-81 s RESISTOR,CHIP 100,1/16W (1005) R867 1-218-941-81 s RESISTOR,CHIP 100,1/16W (1005) R868 1-218-977-11 s RESISTOR,CHIP 100K 1/16W(1005) R869 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R871 1-218-978-11 s RESISTOR,CHIP 120K 1/16W(1005) R901 1-218-973-11 s RESISTOR,CHIP 47K 1/16W (1005) R902 1-218-973-11 s RESISTOR,CHIP 47K 1/16W (1005) R903 1-218-973-11 s RESISTOR,CHIP 47K 1/16W (1005) R904 1-218-951-11 s RESISTOR, CHIP 680 1/16 R905 1-218-951-11 s RESISTOR, CHIP 680 1/16 R906 1-218-990-11 s RESISTOR,CHIP 0 1/16W (1005) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 4-21 VPL-CS7/ES2 (C BOARD ;For VPL-ES2) Ref. No. or Q'ty Part No. SP Description R907 1-218-990-11 s RESISTOR,CHIP 0 1/16W (1005) R908 1-216-811-11 s RESISTOR, CHIP 150 1/16W(1608) R909 1-216-811-11 s RESISTOR, CHIP 150 1/16W(1608) R910 1-216-811-11 s RESISTOR, CHIP 150 1/16W(1608) R911 1-218-953-11 s RESISTOR, CHIP 1K 1/16W R912 1-218-937-11 s RESISTOR, CHIP 47 R913 1-216-811-11 s RESISTOR, CHIP 150 1/16W(1608) R914 1-216-811-11 s RESISTOR, CHIP 150 1/16W(1608) R915 1-216-811-11 s RESISTOR, CHIP 150 1/16W(1608) R916 1-218-953-11 s RESISTOR, CHIP 1K 1/16W R917 1-216-811-11 s RESISTOR, CHIP 150 1/16W(1608) R918 1-216-811-11 s RESISTOR, CHIP 150 1/16W(1608) R919 1-216-811-11 s RESISTOR, CHIP 150 1/16W(1608) R920 1-218-937-11 s RESISTOR, CHIP 47 R921 1-218-941-81 s RESISTOR,CHIP 100,1/16W (1005) R922 1-218-941-81 s RESISTOR,CHIP 100,1/16W (1005) R923 1-218-941-81 s RESISTOR,CHIP 100,1/16W (1005) R924 1-218-945-11 s RESISTOR,CHIP 220 1/16W(1005) R925 1-216-864-11 s CONDUCTOR, CHIP (1608) R926 1-216-864-11 s CONDUCTOR, CHIP (1608) R927 1-216-864-11 s CONDUCTOR, CHIP (1608) R928 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R929 1-218-973-11 s RESISTOR,CHIP 47K 1/16W (1005) R930 1-218-973-11 s RESISTOR,CHIP 47K 1/16W (1005) R931 1-218-973-11 s RESISTOR,CHIP 47K 1/16W (1005) R932 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R933 1-218-990-11 s RESISTOR,CHIP 0 1/16W (1005) R934 1-218-990-11 s RESISTOR,CHIP 0 1/16W (1005) R935 1-218-937-11 s RESISTOR, CHIP 47 R941 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R945 1-218-937-11 s RESISTOR, CHIP 47 R946 1-218-937-11 s RESISTOR, CHIP 47 R947 1-218-937-11 s RESISTOR, CHIP 47 R948 1-218-951-11 s RESISTOR, CHIP 680 1/16 R949 1-218-951-11 s RESISTOR, CHIP 680 1/16 R950 1-218-973-11 s RESISTOR,CHIP 47K 1/16W (1005) R951 1-218-973-11 s RESISTOR,CHIP 47K 1/16W (1005) R952 1-218-973-11 s RESISTOR,CHIP 47K 1/16W (1005) R953 1-218-951-11 s RESISTOR, CHIP 680 1/16 R954 1-218-951-11 s RESISTOR, CHIP 680 1/16 R955 1-218-951-11 s RESISTOR, CHIP 680 1/16 R956 1-218-951-11 s RESISTOR, CHIP 680 1/16 R957 1-218-951-11 s RESISTOR, CHIP 680 1/16 R958 1-218-951-11 s RESISTOR, CHIP 680 1/16 R959 1-218-951-11 s RESISTOR, CHIP 680 1/16 R960 1-218-951-11 s RESISTOR, CHIP 680 1/16 R961 1-216-811-11 s RESISTOR, CHIP 150 1/16W(1608) R962 1-216-811-11 s RESISTOR, CHIP 150 1/16W(1608) R963 1-216-811-11 s RESISTOR, CHIP 150 1/16W(1608) R965 1-216-811-11 s RESISTOR, CHIP 150 1/16W(1608) R966 1-216-811-11 s RESISTOR, CHIP 150 1/16W(1608) R969 1-216-811-11 s RESISTOR, CHIP 150 1/16W(1608) R970 1-216-811-11 s RESISTOR, CHIP 150 1/16W(1608) R971 1-218-953-11 s RESISTOR, CHIP 1K 1/16W R972 1-218-973-11 s RESISTOR,CHIP 47K 1/16W (1005) R973 1-218-973-11 s RESISTOR,CHIP 47K 1/16W (1005) R974 1-218-973-11 s RESISTOR,CHIP 47K 1/16W (1005) R977 1-218-990-11 s RESISTOR,CHIP 0 1/16W (1005) R979 1-216-811-11 s RESISTOR, CHIP 150 1/16W(1608) (C BOARD ;For VPL-ES2) Ref. No. or Q'ty Part No. SP Description R980 1-216-811-11 s RESISTOR, CHIP 150 1/16W(1608) R981 1-216-811-11 s RESISTOR, CHIP 150 1/16W(1608) R982 1-216-811-11 s RESISTOR, CHIP 150 1/16W(1608) R983 1-216-811-11 s RESISTOR, CHIP 150 1/16W(1608) R984 1-216-811-11 s RESISTOR, CHIP 150 1/16W(1608) R985 1-216-811-11 s RESISTOR, CHIP 150 1/16W(1608) R986 1-218-937-11 s RESISTOR, CHIP 47 R987 1-218-937-11 s RESISTOR, CHIP 47 R988 1-218-937-11 s RESISTOR, CHIP 47 R989 1-216-811-11 s RESISTOR, CHIP 150 1/16W(1608) R990 1-216-811-11 s RESISTOR, CHIP 150 1/16W(1608) R991 1-218-990-11 s RESISTOR,CHIP 0 1/16W (1005) R992 1-216-811-11 s RESISTOR, CHIP 150 1/16W(1608) R993 1-208-643-11 s RESISTOR CHIP 22 1/16W (1005) R994 1-208-643-11 s RESISTOR CHIP 22 1/16W (1005) R995 1-218-965-11 s RESISTOR, CHIP 10K 1/16W R996 1-218-990-11 s RESISTOR,CHIP 0 1/16W (1005) R997 1-218-990-11 s RESISTOR,CHIP 0 1/16W (1005) R998 1-218-977-11 s RESISTOR,CHIP 100K 1/16W(1005) R999 1-216-811-11 s RESISTOR, CHIP 150 1/16W(1608) RB102 1-234-372-11 s RES, NETWORK 100X4 (1005) RB108 1-234-372-11 s RES, NETWORK 100X4 (1005) RB109 1-234-372-11 s RES, NETWORK 100X4 (1005) RB110 1-234-372-11 s RES, NETWORK 100X4 (1005) RB111 1-234-372-11 s RES, NETWORK 100X4 (1005) RB112 1-234-372-11 s RES, NETWORK 100X4 (1005) RB401 1-234-370-11 s RES, NETWORK 22X4 (1005) RB402 1-234-370-11 s RES, NETWORK 22X4 (1005) RB403 1-234-370-11 s RES, NETWORK 22X4 (1005) RB404 1-234-370-11 s RES, NETWORK 22X4 (1005) RB405 1-234-370-11 s RES, NETWORK 22X4 (1005) RB406 1-234-370-11 s RES, NETWORK 22X4 (1005) RB407 1-234-371-11 s RES, NETWORK 47X4 (1005) RB408 1-234-371-11 s RES, NETWORK 47X4 (1005) RB409 1-234-371-11 s RES, NETWORK 47X4 (1005) RB410 1-234-371-11 s RES, NETWORK 47X4 (1005) RB411 1-234-371-11 s RES, NETWORK 47X4 (1005) RB412 1-234-371-11 s RES, NETWORK 47X4 (1005) RB413 1-234-371-11 s RES, NETWORK 47X4 (1005) RB414 1-234-371-11 s RES, NETWORK 47X4 (1005) RB415 1-234-370-11 s RES, NETWORK 22X4 (1005) RB501 1-234-370-11 s RES, NETWORK 22X4 (1005) RB601 1-234-370-11 s RES, NETWORK 22X4 (1005) RB651 1-234-370-11 s RES, NETWORK 22X4 (1005) RB701 1-234-372-11 s RES, NETWORK 100X4 (1005) RB705 1-234-372-11 s RES, NETWORK 100X4 (1005) RB707 1-234-372-11 s RES, NETWORK 100X4 (1005) TH702 1-803-382-11 s THERMISTOR (10K) TH801 1-803-615-11 s THERMISTOR, POSITIVE X101 1-795-756-11 s VIBRATOR, CRYSTAL X201 1-813-124-21 s VIBRATOR, CERAMIC X301 1-813-326-21 s VIBRATOR, CRYSTAL X302 1-813-326-21 s VIBRATOR, CRYSTAL X701 1-813-326-21 s VIBRATOR, CRYSTAL www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 4-22 VPL-CS7/ES2 ------- G BOARD ------- Ref. No. or Q'ty Part No. SP Description 1pc A-1067-060-A s MOUNTED CIRCUIT BOARD, G 3pcs 7-682-648-09 s SCREW +PS 3X8(EP-FE/ZNBK/CM2) C101 ! 1-165-529-31 s CAP,AC M/P 0.22U 275 M (B8113) C102 ! 1-113-912-11 s CAPACITOR,CERAMIC 0.0047MF/250V C103 ! 1-113-912-11 s CAPACITOR,CERAMIC 0.0047MF/250V C104 ! 1-165-530-11 s CAPACITOR,FILM(ACROSS)0.47MF C105 1-137-639-11 s CAPACITOR,PE FILM 0.47MF C106 1-117-228-11 s CAPACITOR,FILM 2.2MF/450V C107 ! 1-117-751-11 s CAPACITOR, ELECT 220MF/450V C108 1-162-970-11 s CAPACITOR CERAMIC 0.01MF/25V B C109 1-162-964-11 s CAPACITOR,CERAMIC 1000PF/50V B C110 1-127-715-11 s CAPACITOR,CERAMIC 0.22MF B1608 C111 1-128-403-11 s CAPACITOR,ELECT 47MF/35V(CHIP) C112 1-115-339-11 s CAPACITOR,CERAMIC 0.1MF/50V C201 1-162-970-11 s CAPACITOR CERAMIC 0.01MF/25V B C202 1-162-964-11 s CAPACITOR,CERAMIC 1000PF/50V B C203 1-128-004-11 s CAPACITOR ELECT 10MF/16V(CHIP) C204 1-125-889-11 s CAPACITOR, CERAMIC 2.2MF C205 1-128-403-11 s CAPACITOR,ELECT 47MF/35V(CHIP) C206 1-162-970-11 s CAPACITOR CERAMIC 0.01MF/25V B C207 1-128-403-11 s CAPACITOR,ELECT 47MF/35V(CHIP) C208 1-162-970-11 s CAPACITOR CERAMIC 0.01MF/25V B C209 1-115-339-11 s CAPACITOR,CERAMIC 0.1MF/50V C210 1-137-753-11 s CAPACITOR METALIZED 4700PF C211 1-107-911-11 s CAPACITOR,ELECT 220MF/50V C212 1-115-566-11 s CAPACITOR,CERAMIC 4.7MF B/6.3V C214 1-131-976-11 s CAP, ELECT 820MF C215 1-135-960-91 s CAP, CHIP CERAMIC 10MF B(3225) C216 1-128-946-11 s CAP, ELECT 2200MF / 10V C217 1-135-960-91 s CAP, CHIP CERAMIC 10MF B(3225) C218 1-107-826-11 s CAPACITOR,CHIP CERAMIC 0.1MF C219 1-107-826-11 s CAPACITOR,CHIP CERAMIC 0.1MF C220 1-107-826-11 s CAPACITOR,CHIP CERAMIC 0.1MF C221 1-135-960-91 s CAP, CHIP CERAMIC 10MF B(3225) C222 1-115-339-11 s CAPACITOR,CERAMIC 0.1MF/50V C223 1-126-400-11 s CAPACITOR ELECT 22MF/35V(CHIP) C224 1-135-960-91 s CAP, CHIP CERAMIC 10MF B(3225) C229 1-164-230-11 s CAPACITOR,CERAMIC 220PF/50V C230 1-135-343-11 s CAPACITOR,SOLID ELECT 120MF C234 1-100-026-11 s CAPACITOR, ELECT 220MF(8X6.9) C235 1-107-826-11 s CAPACITOR,CHIP CERAMIC 0.1MF C236 1-126-206-11 s CAPACITOR, ELECT 100MF/6.3V C237 1-107-826-11 s CAPACITOR,CHIP CERAMIC 0.1MF C238 1-126-395-11 s CAPACITOR,ELECT 22MF/16V(CHIP) C240 1-107-826-11 s CAPACITOR,CHIP CERAMIC 0.1MF C241 1-162-927-11 s CAPACITOR,CERAMIC 100PF/50V CH C242 1-165-585-21 s CAPACITOR, CHIP ELECT 47MF CN101 ! 1-691-960-11 o PIN,CONNECTOR (PC BOARD) 3P CN102 ! 1-691-960-21 o PIN, CONNECTOR (PC BOARD) 3P CN201 1-764-782-11 o HOUSING, CONNECTOR 24P D101 ! 6-500-406-01 s DIODE D10XB80 D102 8-719-304-63 s DIODE RM11C (RECTI) D103 ! 8-719-060-06 s DIODE FSF10A60 D104 8-719-510-11 s DIODE D1FS4 D201 8-719-107-13 s DIODE RD18M-B1 D202 8-719-073-01 s DIODE MA111-(K8).S0 D203 8-719-979-64 s DIODE UF4005PKG23 D204 8-719-055-30 s DIODE D1FS4A-TA (G BOARD) Ref. No. or Q'ty Part No. SP Description D205 8-719-037-57 s DIODE RD39SB-T1 D206 8-719-510-09 s DIODE D10SC6M (RECTI) D207 8-719-073-01 s DIODE MA111-(K8).S0 D209 8-719-510-12 s DIODE D10SC4M D210 8-719-073-01 s DIODE MA111-(K8).S0 D212 8-719-073-01 s DIODE MA111-(K8).S0 D214 8-719-078-04 s DIODE EC31QS03L-TE12L D215 8-719-073-01 s DIODE MA111-(K8).S0 D216 8-719-073-01 s DIODE MA111-(K8).S0 D217 8-719-073-01 s DIODE MA111-(K8).S0 D218 8-719-073-01 s DIODE MA111-(K8).S0 D219 8-719-037-54 s DIODE RD30SB-T1 F101 ! 1-576-232-12 s FUSE (H.B.C.) FH101 1-533-223-11 s CLIP,FUSE FH102 1-533-223-11 s CLIP,FUSE IC102 8-759-382-19 o IC MC34262DR2 IC201 6-705-768-01 s IC MCZ3001UB IC202 8-759-183-53 s IC TL431CPK-E2 IC203 8-759-100-93 s IC UPC393G2 IC204 8-759-592-79 s IC BA00AST IC205 8-759-713-98 s IC LTC1772CS6 IC206 6-704-954-01 s IC AIC1117A-50PYJTR L101 ! 1-456-134-21 s COIL, LINE FILTER L102 ! 1-456-632-11 s CHOKE COIL 550MMH L103 ! 1-456-133-31 s COIL, CHOKE 200UH L201 1-409-527-41 s COIL, CHOKE 4.7UH L202 1-409-527-41 s COIL, CHOKE 4.7UH L204 1-409-529-41 s COIL, CHOKE 10UH L205 1-409-527-41 s COIL, CHOKE 4.7UH L207 1-409-527-41 s COIL, CHOKE 4.7UH PH201 8-749-016-82 s PHOTO COUPLER PC123GY2 PH202 8-749-016-82 s PHOTO COUPLER PC123GY2 Q101 ! 8-729-041-65 s TRANSISTOR 2SK2195F04 Q102 8-729-230-27 s TRANSISTOR 2SA1213Y-TE12L Q201 8-729-052-29 s TRANSISTOR 2SK2876-01MR-F122 Q202 8-729-052-29 s TRANSISTOR 2SK2876-01MR-F122 Q203 8-729-216-22 s TRANSISTOR 2SA1162-G Q204 8-729-230-49 s TRANSISTOR 2SC2712-YG Q205 8-729-047-32 s TRANSISTOR SI4425DY-T1 Q206 8-729-047-32 s TRANSISTOR SI4425DY-T1 Q207 8-729-029-14 s TRANSISTOR DTC144EUA-T106 Q209 6-550-126-01 s TRANSISTOR SI4403DY-T1 Q210 8-729-029-14 s TRANSISTOR DTC144EUA-T106 Q211 8-729-029-14 s TRANSISTOR DTC144EUA-T106 Q212 8-729-029-14 s TRANSISTOR DTC144EUA-T106 Q213 8-729-029-14 s TRANSISTOR DTC144EUA-T106 Q214 8-729-029-14 s TRANSISTOR DTC144EUA-T106 Q215 8-729-029-14 s TRANSISTOR DTC144EUA-T106 R101 ! 1-219-754-11 s RESISTOR(SURGE RESISTANT)680K R102 1-249-393-11 s RES,CARBON 10 1/4W R104 1-219-738-11 s RES, 0.08 (RESISTOR, METAL) R105 1-218-899-11 s RESISTOR,CHIP 150K 1/10W(1608) R106 1-218-907-11 s RESISTOR,CHIP 330K 1/10W(1608) R107 1-218-907-11 s RESISTOR,CHIP 330K 1/10W(1608) R108 1-218-907-11 s RESISTOR,CHIP 330K 1/10W(1608) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 4-23 VPL-CS7/ES2 (G BOARD) Ref. No. or Q'ty Part No. SP Description R110 1-216-817-11 s RESISTOR,CHIP 470 1/10W 1608 R111 1-218-871-11 s RESISTOR,CHIP 10K 1/10W (1608) R112 1-218-871-11 s RESISTOR,CHIP 10K 1/10W (1608) R113 1-218-907-11 s RESISTOR,CHIP 330K 1/10W(1608) R114 1-218-907-11 s RESISTOR,CHIP 330K 1/10W(1608) R115 1-218-907-11 s RESISTOR,CHIP 330K 1/10W(1608) R116 1-218-907-11 s RESISTOR,CHIP 330K 1/10W(1608) R117 1-216-837-11 s RESISTOR,CHIP 22K 1/16W 1608 R118 1-218-871-11 s RESISTOR,CHIP 10K 1/10W (1608) R119 1-216-829-11 s RESISTOR,CHIP 4.7K 1/10W(1608) R120 1-216-833-11 s RESISTOR,CHIP 10K 1/10W (1608) R201 1-218-875-11 s RESISTOR,CHIP 15K 1/10W (1608) R202 1-218-859-11 s RESISTOR,CHIP 3.3K 1/10W(1608) R203 1-218-907-11 s RESISTOR,CHIP 330K 1/10W(1608) R204 1-218-907-11 s RESISTOR,CHIP 330K 1/10W(1608) R205 1-218-907-11 s RESISTOR,CHIP 330K 1/10W(1608) R206 1-249-417-11 s RESISTOR,CARBON 1K 1/4W(SMALL) R207 1-218-859-11 s RESISTOR,CHIP 3.3K 1/10W(1608) R208 1-218-875-11 s RESISTOR,CHIP 15K 1/10W (1608) R209 1-216-819-11 s RESISTOR,CHIP 680 1/10W 1608 R210 1-216-833-11 s RESISTOR,CHIP 10K 1/10W (1608) R211 1-216-809-11 s RESISTOR,CHIP 100 1/10W 1608 R212 1-249-389-11 s RES,CARBON 4.7 1/4W R213 1-202-933-61 s RESISTOR, FUSE 0.1 1/2W R214 1-216-797-11 s RESISTOR,CHIP 10 1/10W 1608 R215 1-216-833-11 s RESISTOR,CHIP 10K 1/10W (1608) R216 1-216-797-11 s RESISTOR,CHIP 10 1/10W 1608 R217 1-216-833-11 s RESISTOR,CHIP 10K 1/10W (1608) R218 1-216-815-11 s RESISTOR,CHIP 330 1/10W 1608 R219 1-243-803-71 s RES, OXIDE METAL FILM 0.33 R220 1-216-841-11 s RESISTOR, CHIP 47K 1/10W 1608 R221 1-216-833-11 s RESISTOR,CHIP 10K 1/10W (1608) R222 1-216-821-11 s RESISTOR,CHIP 1.0K 1/10W(1608) R223 1-216-841-11 s RESISTOR, CHIP 47K 1/10W 1608 R224 1-216-833-11 s RESISTOR,CHIP 10K 1/10W (1608) R225 1-216-845-11 s RESISTOR,CHIP 100K 1/10W(1608) R226 1-216-841-11 s RESISTOR, CHIP 47K 1/10W 1608 R227 1-216-827-11 s RESISTOR, CHIP 3.3K 1/10W 1608 R228 1-216-841-11 s RESISTOR, CHIP 47K 1/10W 1608 R229 1-216-821-11 s RESISTOR,CHIP 1.0K 1/10W(1608) R230 1-216-827-11 s RESISTOR, CHIP 3.3K 1/10W 1608 R231 1-216-817-11 s RESISTOR,CHIP 470 1/10W 1608 R232 1-216-821-11 s RESISTOR,CHIP 1.0K 1/10W(1608) R233 1-218-873-11 s RESISTOR,CHIP 12K 1/10W (1608) R234 1-218-863-11 s RESISTOR,CHIP 4.7K 1/10W(1608) R235 1-216-825-11 s RESISTOR,CHIP 2.2K 1/10W 1608 R236 1-218-871-11 s RESISTOR,CHIP 10K 1/10W (1608) R237 1-216-841-11 s RESISTOR, CHIP 47K 1/10W 1608 R238 1-216-833-11 s RESISTOR,CHIP 10K 1/10W (1608) R239 1-216-825-11 s RESISTOR,CHIP 2.2K 1/10W 1608 R240 1-216-837-11 s RESISTOR,CHIP 22K 1/16W 1608 R241 1-216-833-11 s RESISTOR,CHIP 10K 1/10W (1608) R242 1-216-833-11 s RESISTOR,CHIP 10K 1/10W (1608) R243 1-216-841-11 s RESISTOR, CHIP 47K 1/10W 1608 R244 1-216-841-11 s RESISTOR, CHIP 47K 1/10W 1608 R245 1-218-875-11 s RESISTOR,CHIP 15K 1/10W (1608) R246 1-218-879-11 s RESISTOR,CHIP 22K 1/10W (1608) R247 1-218-859-11 s RESISTOR,CHIP 3.3K 1/10W(1608) R250 1-216-833-11 s RESISTOR,CHIP 10K 1/10W (1608) (G BOARD) Ref. No. or Q'ty Part No. SP Description R251 1-218-901-11 s RESISTOR,CHIP 180K 1/10W(1608) R252 1-218-883-11 s RESISTOR,CHIP 33K 1/10W (1608) R253 1-219-611-21 s RESISTOR, CHIP 0.047 1W R254 1-218-891-11 s RESISTOR,CHIP 68K 1/10W (1608) R255 1-216-813-11 s RESISTOR, CHIP 220 1/10W 1608 R256 1-216-813-11 s RESISTOR, CHIP 220 1/10W 1608 R257 1-216-833-11 s RESISTOR,CHIP 10K 1/10W (1608) R258 1-216-835-11 s RESISTOR,CHIP 15K 1/10W R259 1-216-829-11 s RESISTOR,CHIP 4.7K 1/10W(1608) R260 1-216-833-11 s RESISTOR,CHIP 10K 1/10W (1608) R261 1-216-829-11 s RESISTOR,CHIP 4.7K 1/10W(1608) R262 1-216-835-11 s RESISTOR,CHIP 15K 1/10W R263 1-216-833-11 s RESISTOR,CHIP 10K 1/10W (1608) R264 1-216-833-11 s RESISTOR,CHIP 10K 1/10W (1608) R265 1-216-825-11 s RESISTOR,CHIP 2.2K 1/10W 1608 R266 1-216-833-11 s RESISTOR,CHIP 10K 1/10W (1608) R267 1-216-835-11 s RESISTOR,CHIP 15K 1/10W R268 1-216-829-11 s RESISTOR,CHIP 4.7K 1/10W(1608) R269 1-216-797-11 s RESISTOR,CHIP 10 1/10W 1608 R301 1-216-864-11 s CONDUCTOR, CHIP (1608) T202 ! 1-437-380-22 s TRANSFORMER, CONVERTER TH101 ! 1-810-509-11 s THERMISTOR,POWER VDR101 ! 1-803-830-31 s VARISTOR (ERZV14D621) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 4-24 VPL-CS7/ES2 ------- H BOARD ------- Ref. No. or Q'ty Part No. SP Description 1pc A-1078-661-A s MOUNTED CIRCUIT BOARD, H C10 1-125-777-11 s CAPACITOR CERAMIC 0.1MF/10V CN10 1-691-491-21 s CONNECTOR, FFC/FPC 12P D10 8-719-045-51 s DIODE SEC2422C D11 8-719-045-51 s DIODE SEC2422C D12 8-719-024-77 s DIODE HN1D03FU-TE85L D13 8-719-024-77 s DIODE HN1D03FU-TE85L Q10 8-729-028-73 s TRANSISTOR DTA114EUA-T106 Q11 8-729-028-73 s TRANSISTOR DTA114EUA-T106 Q12 8-729-427-72 s TRANSISTOR XP4501-TXE R10 1-218-943-11 s RESISTOR,CHIP 150 1/16W R11 1-218-943-11 s RESISTOR,CHIP 150 1/16W R12 1-218-944-11 s RESISTOR,CHIP 180 1/16W R13 1-218-958-11 s RESISTOR,CHIP 2.7K 1/16W(1005) R14 1-218-944-11 s RESISTOR,CHIP 180 1/16W R15 1-218-954-11 s RESISTOR, CHIP 1.2K 1/16W R16 1-218-951-11 s RESISTOR, CHIP 680 1/16 R17 1-218-948-11 s RESISTOR CHIP 390 1/16W (1005) R18 1-218-941-81 s RESISTOR,CHIP 100,1/16W (1005) R19 1-218-946-11 s RESISTOR,CHIP 270 1/16W R20 1-218-941-81 s RESISTOR,CHIP 100,1/16W (1005) R21 1-218-945-11 s RESISTOR,CHIP 220 1/16W(1005) R22 1-218-941-81 s RESISTOR,CHIP 100,1/16W (1005) R23 1-218-941-81 s RESISTOR,CHIP 100,1/16W (1005) R24 1-218-961-11 s RESISTOR, CHIP 4.7K 1/16W R25 1-218-973-11 s RESISTOR,CHIP 47K 1/16W (1005) R26 1-218-973-11 s RESISTOR,CHIP 47K 1/16W (1005) R27 1-218-973-11 s RESISTOR,CHIP 47K 1/16W (1005) S10 1-771-105-11 s SWITCH, TACTILE S11 1-771-105-11 s SWITCH, TACTILE S12 1-771-105-11 s SWITCH, TACTILE S13 1-771-105-11 s SWITCH, TACTILE S14 1-786-651-11 s TACTILE SWITCH S15 1-771-105-11 s SWITCH, TACTILE ------- L BOARD ------- Ref. No. or Q'ty Part No. SP Description 1pc A-1078-662-A s MOUNTED CIRCUIT BOARD, L CN70 1-778-506-21 s PIN, CONNECTOR 2P D70 8-719-084-01 s DIODE (LED) NSCW215T -------- NR BOARD -------- Ref. No. or Q'ty Part No. SP Description 1pc A-1061-840-A s MOUNTED CIRCUIT BOARD, NR C80 1-117-370-11 s CAPACITOR CERAMIC 10MF (3216) CN80 1-770-620-21 s PIN, CONNECTOR 3P IC001 6-704-826-01 s IC KRM-TR303E-TP R80 1-218-937-11 s RESISTOR, CHIP 47 R81 1-218-941-81 s RESISTOR,CHIP 100,1/16W (1005) -------------------- Q BOARD ;For VPL-CS7 -------------------- Ref. No. or Q'ty Part No. SP Description 1pc A-1061-842-A s MOUNTED CIRCUIT BOARD, Q C1 1-128-399-11 s CAPACITOR ELECT 330MF/16V(CHIP C2 1-128-399-11 s CAPACITOR ELECT 330MF/16V(CHIP C3 1-128-399-11 s CAPACITOR ELECT 330MF/16V(CHIP CN1 1-770-626-21 s PIN, CONNECTOR (L TYPE) 9P CN2 1-784-828-11 s CONNECTOR, D SUB R1 1-216-805-11 s RESISTOR,CHIP 47 1/10W 1608 R2 1-216-864-11 s CONDUCTOR, CHIP (1608) R3 1-216-864-11 s CONDUCTOR, CHIP (1608) R4 1-216-805-11 s RESISTOR,CHIP 47 1/10W 1608 R5 1-216-864-11 s CONDUCTOR, CHIP (1608) R6 1-216-864-11 s CONDUCTOR, CHIP (1608) R7 1-216-864-11 s CONDUCTOR, CHIP (1608) R8 1-216-864-11 s CONDUCTOR, CHIP (1608) R9 1-216-841-11 s RESISTOR, CHIP 47K 1/10W 1608 R10 1-216-841-11 s RESISTOR, CHIP 47K 1/10W 1608 R11 1-216-841-11 s RESISTOR, CHIP 47K 1/10W 1608 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 4-25 VPL-CS7/ES2 --------------------- QA BOARD ;For VPL-ES2 --------------------- Ref. No. or Q'ty Part No. SP Description 1pc A-1061-844-A s MOUNTED CIRCUIT BOARD, QA C601 1-126-205-11 s CAPACITOR,ELECT 47MF/6.3 C602 1-162-970-11 s CAPACITOR CERAMIC 0.01MF/25V B C603 1-126-205-11 s CAPACITOR,ELECT 47MF/6.3 C604 1-162-970-11 s CAPACITOR CERAMIC 0.01MF/25V B C605 1-126-205-11 s CAPACITOR,ELECT 47MF/6.3 C606 1-162-970-11 s CAPACITOR CERAMIC 0.01MF/25V B CN601 1-770-626-21 s PIN, CONNECTOR (L TYPE) 9P J601 1-816-949-11 o PIN JACK 3P R601 1-216-811-11 s RESISTOR, CHIP 150 1/16W(1608) R602 1-216-811-11 s RESISTOR, CHIP 150 1/16W(1608) R603 1-216-811-11 s RESISTOR, CHIP 150 1/16W(1608) R604 1-216-811-11 s RESISTOR, CHIP 150 1/16W(1608) R605 1-216-811-11 s RESISTOR, CHIP 150 1/16W(1608) R606 1-216-811-11 s RESISTOR, CHIP 150 1/16W(1608) ------- S BOARD ------- Ref. No. or Q'ty Part No. SP Description CN501 1-770-624-21 s PIN, CONNECTOR 7P D501 8-719-053-18 s DIODE 1SR154-400TE-25 D502 8-719-053-18 s DIODE 1SR154-400TE-25 RV501 1-227-596-11 s POTENTIOMETER S501 1-786-591-11 s SWITCH, MICRO S502 1-786-591-11 s SWITCH, MICRO --------------------- SA BOARD ;For VPL-CS7 --------------------- Ref. No. or Q'ty Part No. SP Description 1pc A-1061-845-A s MOUNTED CIRCUIT BOARD, SA C701 1-162-970-11 s CAPACITOR CERAMIC 0.01MF/25V B C702 1-107-826-11 s CAPACITOR,CHIP CERAMIC 0.1MF C703 1-117-370-11 s CAPACITOR CERAMIC 10MF (3216) C704 1-107-826-11 s CAPACITOR,CHIP CERAMIC 0.1MF C705 1-100-119-12 s CAPACITOR,DOUBLE LAYERS 0.47F CN701 1-770-622-21 s PIN, CONNECTOR 5P CN702 1-580-057-11 s PIN,CONNECTOR 4P CN703 1-580-056-21 s PIN,CONNECTOR 3P D701 8-719-055-30 s DIODE D1FS4A-TA IC701 6-705-943-01 s IC MXS3125GL IC703 8-759-579-31 s IC PQ20WZ1U Q701 8-729-047-32 s TRANSISTOR SI4425DY-T1 R701 1-216-797-11 s RESISTOR,CHIP 10 1/10W 1608 R704 1-216-825-11 s RESISTOR,CHIP 2.2K 1/10W 1608 R705 1-216-829-11 s RESISTOR,CHIP 4.7K 1/10W(1608) R706 1-216-825-11 s RESISTOR,CHIP 2.2K 1/10W 1608 R707 1-216-829-11 s RESISTOR,CHIP 4.7K 1/10W(1608) R708 1-216-833-11 s RESISTOR,CHIP 10K 1/10W (1608) R709 1-215-864-00 s RESISTOR,METAL FILM 150 1W R710 1-215-864-00 s RESISTOR,METAL FILM 150 1W TH701 1-803-382-11 s THERMISTOR (10K) --------------------- SA BOARD ;For VPL-ES2 --------------------- Ref. No. or Q’ty Part No. SP Description 1pc A-1067-069-A s MOUNTED CIRCUIT BOARD, SA C701 1-162-970-11 s CAPACITOR CERAMIC 0.01MF/25V B C702 1-107-826-11 s CAPACITOR,CHIP CERAMIC 0.1MF C703 1-117-370-11 s CAPACITOR CERAMIC 10MF (3216) C704 1-107-826-11 s CAPACITOR,CHIP CERAMIC 0.1MF CN701 1-770-622-21 s PIN, CONNECTOR 5P CN702 1-580-057-11 s PIN,CONNECTOR 4P CN703 1-580-056-21 s PIN,CONNECTOR 3P R701 1-216-797-11 s RESISTOR,CHIP 10 1/10W 1608 TH701 1-803-382-11 s THERMISTOR (10K) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 4-26 VPL-CS7/ES2 ---------------------------------------- PACKING MATERIALS & SUPPLIED ACCESSORIES ---------------------------------------- Ref. No. or Q'ty Part No. SP Description 1pc 1-476-555-21 s REMOTE COMMANDER (RM-PJ2) (INCLUDING LITHIUM BATTERY CR2025) 1pc 9-885-010-99 s COVER, BATTERY (FOR RM-PJ2) 1pc ! - - - s CORD, POWER (See 1-4. Note on Power Cord) 1pc 1-791-992-31 s CABLE ASSY(15PDSUBCONNECTORX2) 1pc 2-148-331-01 s CD-ROM (CS7) 1pc ! 4-099-113-01 s FILTER (E1) 1pc 4-096-087-02 s CASE, CARRYING ------- V BOARD ------- Ref. No. or Q'ty Part No. SP Description 1pc A-1078-663-A s MOUNTED CIRCUIT BOARD, V C60 1-164-943-11 s CAPACITOR,CHIP CERAMIC 0.01MF CN60 1-770-621-21 s PIN, CONNECTOR 4P R60 1-208-699-11 s RESISTOR,CHIP 4.7K 1/16W(1005) S60 1-762-984-11 s SWITCH, PUSH TH60 1-803-382-11 s THERMISTOR (10K) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 5-1 VPL-CS7/ES2 5-1 Overall Overall Section 5 Block Diagrams Emulator IIC Exit Cont CVBS Y C R/R-Y G/Y B/B-Y Uart DFBK HS/CS DHS VS DVS COAST SID (VPL-CS7) (VPL-ES2) FAN_A IIC 400K FAN_B FAN_Prot INT/No INT FAN_1 FAN_C FAN_2 H Pol FAN_3 V Pol FAN_D LAMP_POWER IIC 100K LAMP_ON Au_Mute LAMP_PROT TILT_X LAMP_COVER SA TILT_Y Audio_R MOT_C Audio_L MOT_EN POS_DET CPU & PW Write 5V-1 5V-2 5V-3 3.3V-3 3.3V-2 2.5V-3 1.8V 1.55V Key_0 Key_4 Power_LED TEMP_LED LAMP_LED PSAVE_LED CIRCS LED_Cont G BOARD SPEAKER SA BOARD S BOARD H BAORD L BOARD CPU & PW Write THERM FUSE BALLAST NR BOARD G BOARD QA BOARD C.DEC PW2200 Scan Converter PW168 TG/Gamma CXD3536 P.DRV CXA7005 TG Buff 74VHCT541 LCD Panel (Red) LCD Panel (Green) SID Buff SID Buff X'tal PW Reset TG Reset EEPROM M24C64 SPRED ICS332 4M Flash ROM MBM29LV800TA IIC SW P.DRV CXA7005 Main CPU HD64 (New) EEPROM M24C64 232C SW Sync Sep M52347 Sync Sep CXA2171 Sync Sel Logic X'tal 27MHz CX P.DRV CXA7005 SID Buff DDC 24LC21 Audio Proces Audio Amp CN 2P 1.5V 1.8V J901 S3V POWER SUPPLY EXAMPLE Accelerometer ADXL202JE Motor Cont Motor Drive BA6288 CN 5P Buff LMC7101 CN FPC12P B to B 70P Exit SW CN 4P CN12P SW Buff Buff CN 2P CN 5P Motor Drv Motor Drv Motor Drv LCD Panel (Blue) CN FPC23P CN FPC23P CN 3P CN 3P CN 3P CN 3P OR 3.3V 3.3V 5V 15V 15V 15V S3V 9V 13.5V 5V 15V 13.5V 5V 15V 13.5V 5V 15V CN 6P IC204 IC205 IC303 IC304 IC302 IC403 IC404 IC405 Q701 IC306 Q602 Q601 Q502 Q501 Q652 Q651 IC407 IC408 IC409 IC410 IC651 IC501 IC601 IC703 IC705 CN702 CN703 Q806 IC807 IC808 IC809 CN809 CN810 CN811 CN812 CN807 CN806 Q808 Q807 CN803 CN805 CN905 CN806 IC908 J902 CN 24P 5V Reg 5V Reg 3.3V Reg 2.5V Reg 1.8V Reg 1.55V Reg CN804 IC803 IC805 IC802 IC804 IC806 SIG Sel EL5634IUZ -T7 (VPL-ES2 0nly) RGB Amp (VPL-CS7) SIG Sel EL5634IUZ -T7 (VPL-ES2) Sync Drv SN75453 BPSR (VPL-CS7) CN 5P CN 5P CN815 9V 5V 5V 5V IC203 IC102 X201 IC201 9V 2.5V 5V 9V 13.5V 15V 3.3V 2.5V 1.8V 3.3V 2.5V 1.5V 1.8V 3.3V 3.3V S5V CN902 CN901 CN904 IC901 IC301 IC401 X301 IC911 IC913 IC915 IC914 IC801 15V 3.3V 15V CN601 CN501 CN651 3.3V 15V CN FPC23P Overall w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 5-2 VPL-CS7/ES2 5-2 G G PFC (Phase compensation ) RESONANT MODE SW REG CONT. Starter Switching Circuit +17V OUT +6V OUT Error amp. F.B OVP Vcc OVER CURRENT DET. OCP Noise Filter AC INLET with NOISE FILTER BALLAST OUT 200W D3.3V OUT DC/DC OVP LATCH Power Thermistor SUB5V OUT FAN+B OUT DC/DC DELAY PCONT FAN CONT1 POWER PROT PPROT From each G Board 5V REG G w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 5-3 VPL-CS7/ES2 5-3 H, L, NR, SA, V H, L, NR, SA, V CN 3P to C CN 4P to C CN 2P to C FPC 12P to C SIRCS 5V-1 NR SW (FLT_Cov) 5V-1 V SIRCS Filter _Cover TH Lamp_tem p Logo LED LED Vcc L Lamp_Cont Function Key Function Key LED Logic H SA Accelerometer MXD2020E FAN CONT BA00 (VPL-CS7 Only) Off & Go Capacitor (VPL-CS7 Only) H L NR SA V w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com VPL-CS7/ES2 6-1 6-1 Section 6 Schematic Diagrams Index Board Name Page C 6-2 G 6-15 H 6-17 NR 6-18 QA (VPL-ES2) 6-18 Q (VPL-CS7) 6-18 SA 6-19 S 6-19 V 6-19 Frame Wiring 6-20 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com VPL-CS7/ES2 6-2 6-2 2 3 4 5 A B C D E F G H 1 C (1/10) C (1/10) C (1/10) 1.8V 3.3V-2 1.8V 10V 0.1 B C117 10V 0.1 B C116 10V 0.1 B C118 10V 0.1 B C120 1608 16V 0.22 B C102 10V 0.047 B C113 1608 16V 0.22 B C103 10V 0.047 B C109 50V 1000p B C110 1608 16V 0.22 B C104 10V 0.047 B C114 10V 0.1 B C125 10V 0.1 B C132 10V 0.1 B C133 10V 0.1 B C139 10V 0.1 B C137 10V 0.1 B C141 10V 0.1 B C145 10V 0.1 B C147 10V 0.1 B C149 R131 1/16W CHIP XX R136 1/16W CHIP XX R132 1/16W CHIP 10k R134 1/16W CHIP XX R135 1/16W CHIP XX R130 1/16W CHIP 1M C142 50V 15p CH 3.3V-2 10V 0.1 B C152 10V 0.1 B C153 10V 0.1 B C154 10V 0.1 B C155 10V 0.1 B C150 10V 0.1 B C146 10V 0.1 B C140 3.3V-3 10V 0.1 B C126 10V 0.1 B C127 10V 0.1 B C128 10V 0.1 B C129 10V 0.1 B C130 10V 0.1 B C131 10V 0.1 B C136 10V 0.1 B C123 C143 50V 15p CH 10V 0.1 B C119 10V 0.1 B C121 1/16W RN-CP 3.3k R115 16V 3900p B C112 16V 0.039 C111 100 RB108 100 RB109 100 RB110 100 RB111 100 RB112 100 RB102 JL130 JL131 JL132 JL134 CHIP 100 R145 1/16W CHIP 100 R146 1/16W CHIP 100 R147 1/16W CHIP 100 R149 1/16W CLAMP SDA_PW SCL_PW CHIP XX R116 CHIP XX R118 6.3V 47 C134 6.3V 47 C115 6.3V 47 C106 6.3V 47 C107 6.3V 47 C108 6.3V 47 C156 6.3V 47 C138 L102 1uH L101 1uH L103 1uH 0uH FB101 0uH FB105 0uH FB106 0uH FB102 XX C135 6.3V 47 C157 V_IN HS VS CHIP 0 R129 CHIP 0 R126 27MHz X101 C144 10V 0.1 B C151 10V B 0.1 C148 10V 0.1 B 1/16W CHIP 10k R138 6.3V 47 C105 10V 0.1 B C101 5 4 3 2 1 S-80928CNMC-G8Y-T2 IC103 RESET OUT VDD VSS NC CD JL107 CHIP XX R128 CHIP XX R125 1/16W CHIP 220 R110 1/16W CHIP 220 R109 1/16W CHIP 220 R112 1/16W CHIP 220 R111 1/16W CHIP 220 R114 1/16W CHIP 220 R113 1/16W CHIP 10k R127 CHIP XX R117 INTERLACE 1/16W CHIP 10k R158 1/16W CHIP 10k R159 CHIP XX R160 L104 1uH 0uH FB103 6.3V 47 C158 GVS GHS JL139 1/16W CHIP XX R164 1/16W CHIP XX R165 1/16W CHIP XX R166 1/16W CHIP XX R167 1/16W CHIP XX R168 1/16W CHIP 10k R169 1/16W CHIP 10k R170 1/16W CHIP 10k R171 1/16W CHIP 10k R172 1/16W CHIP 10k R173 1/16W CHIP 10k R174 1/16W CHIP 10k R175 1/16W CHIP 10k R176 1/16W CHIP 10k R177 1/16W CHIP XX R178 1/16W CHIP 10k R179 TP101 XX JL135 JL136 CHIP R150 47 1/16W CHIP R151 47 1/16W RST_COM I O ADJ AIC1117A-18PYJTR IC101 1.8V_REG XX C162 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60 61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80 81 82 83 84 85 86 87 88 89 90 91 92 93 94 95 96 97 98 99 100 101 102 103 104 105 106 107 108 109 110 111 112 113 114 115 116 117 118 119 120 121 122 123 124 125 126 127 128 129 130 131 132 133 134 135 136 137 138 139 140 141 142 143 144 145 146 147 148 149 150 151 152 153 154 155 156 157 158 159 160 161 162 163 164 165 166 167 168 169 170 171 172 173 174 175 176 177 178 179 180 181 182 183 184 185 186 187 188 189 190 191 192 193 194 195 196 197 198 199 200 201 202 203 204 205 206 207 208 PW2200B-05L IC102 CDEC_ADCONVERTER RTERM DVDD RX2P RX2M DGND RX1P RX1M DGND RX0P RX0M DGND RXCP RXCM DVDD DGND1 DVDD1 PGND PVD FILT PVD PGND PVD PGND ALVDD ALVDD ALGND ALGND AVDD AVDD AGND AGND AVDD RED1 AGND RED2 AVDD AGND AVDD AGND GRN1 SOG1 AGND GRN2 SOG2 AVDD AGND AVDD AGND BLU1 AGND BLU2 AVDD TMDSEN HDCPEN SRGBEN GPIO24 GPIO25 GPIO27 ADR2 ADR5 ADR6 GPIO3 GPIO4 GPIO5 GPIO11 GPIO12 GPIO13 EXTINT2 EXTINT1 EXTINT0 EXTINT GPIO14 GPIO15 SDA2 SCL2 iTEST_EN VDDQ3 VSSQ HS1 VS1 HS2 VS2 GPIO6 COAST CLAMP DOE VBIVALID VDDQ3 VSSQ GPIO16 GPIO17 GPIO18 VDD1 VSS VSS GPIO19 GPIO20 GPIO21 RESET GPIO31 DBE0 DBE1 DBE2 DBE3 DBE4 DBE5 DBE6 VDDQ3 VSSQ DBE7 DGE0 DGE1 DGE2 DGE3 DGE4 DGE5 DGE6 DGE7 DRE0 DRE1 DRE2 DRE4 DRE5 DRE6 DRE7 DRE3 DCLK DPEN DHS DFBK DVS DFIELD DRO7 DRO6 DRO5 DRO4 VSS VDD1 DRO3 DRO2 DRO1 DRO0 DGO7 VDDQ3 VSSQ DGO6 DGO5 DGO4 DGO3 DGO2 DGO1 DGO0 DBO7 DBO6 DBO5 DBO4 DBO3 DBO2 DBO1 DBO0 GPIO26 GPIO22 VDD1 GPIO23 VSS SDA VDDQ3 SCL VSSQ SCL1 VDDQ3 SDA1 VSSQ RESETPOL VDDQ3 GPIOSEL VSSQ XOUT XIN TAVSS TAVDD SYSCLKT SYSHCLKT TESTEN GCLKT DVSSPLL NC NC NC NC NC DVDDPLL AVSSPLL AVDDPLL TAVSSPST TAVD33 NC NC NC NC NC NC NC NC DVDD1 DGND1 DVDD1 DGND1 R133 1/16W CHIP 1k JL103 GBUS TO 3/10 TO 3/10 CHIP 0 R121 CHIP 0 R119 CHIP 0 R120 GGE[2] GGE[1] GBE[4] GBE[6] GBE[5] GBE[3] GBE[2] GBE[1] GGE[0] GBE[0] GBE[7] GCOAST B SC G SY CVBS R VSYNC HSYNC GGE[3] GGE[4] GGE[5] GGE[6] GGE[7] GRE[0] GRE[1] GRE[2] GRE[4] GRE[5] GRE[6] GRE[7] GRE[3] GCLK GHS GFBK GVS TO 10/10 TO 8/10 TO 2/10,8/10 TO 2/10,8/10 TO 2/10 TO 3/10 TO 8/10 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com VPL-CS7/ES2 2 3 4 5 1 6-3 6-3 A B C D E F G H C (2/10) C (2/10) H_SYNC V_SYNC 1/16W CHIP 1k R211 1/16W CHIP 1k R212 1/16W CHIP 1k R213 1/16W CHIP 1k R214 10V 0.1 B C205 10V 0.1 B C206 1SS355 D201 LIMITER 1SS355 D202 LIMITER 10V 0.1 B C207 10V 0.1 B C208 1005 50V 1000p B C210 1/16W CHIP 47 R248 1/16W CHIP 220 R246 16V 220p CH C229 1/16W CHIP 47 R249 1/16W CHIP 47k R241 1/16W RN-CP 3.3k R244 1/16W CHIP 4.7k R237 1/16W CHIP 2.2k R247 50V 100p CH C227 10V 0.068 B C215 2012 10V 4.7 F C216 1/16W CHIP 10k R229 2012 10V 4.7 F C217 1/16W CHIP 47 R250 16V 0.01 B C225 3216 10V 10 C218 F 20 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 M52347FP-TE IC202 PC_SYNC_SEP H.STATE V.STATE CLAMPSW GREENIN GND C/H C/H_DET V_IN V_DET VTIMING GATESW VS/S_IN VS/S_OUT VD HD HD VCC CLAMP H.POL V.POL CLAMP TIMING HN1B01FU-TE85R Q202 LIMITER HN1B01FU-TE85R Q203 LIMITER SOG 1/16W RN-CP 62k R228 2012 10V 4.7 F C209 1608 10V 0.47 B C211 5V-3 1uH L201 1608 6.3V 1 B C232 16V 0.01 B C233 1/16W CHIP 47 R254 1/16W CHIP 47 R255 1/16W RN-CP 10k R251 2SA1576A-T106-QR Q204 BUFFER 1608 6.3V 1 B C221 16V 0.01 B C234 3.3V-3 HS VS V_POL H_POL CLAMP 10V 0.1 B C212 10V 0.1 B C228 1/16W CHIP 100 R235 1/16W CHIP 100 R234 1608 16V 0.22 B C220 1/16W RN-CP 1k R256 10V 0.1 B C231 I2C_100K 20 19 18 17 16 15 14 13 12 11 1 2 3 4 5 6 7 8 9 10 SN74LV244APWR IC205 SYNC_SELECT DTV IN0 OUT4 IN1 OUT5 IN2 OUT6 IN3 OUT7 GND IN7 OUT3 IN6 OUT2 IN5 OUT1 IN4 OUT0 PC VCC PC_DTV 10V 0.1 B C236 CHIP XX R218 CHIP XX R219 CHIP 10 R204 1/16W JL201 JL202 1608 16V 0.1 B C237 1/16W CHIP 330k R262 1608 6.3V 1 B C238 1/16W CHIP 47 R263 1/16W CHIP 47 R264 JL203 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 CXA2171AQ-T6 IC203 DTV_SYNC_SEP P1 IN3_1 P2 IN3_2 P3 IN3_3 P4 IN3_H P5 IN3_V P6 GND3 P7 IN4_1 P8 IN4_2 P9 IN4_3 P10 IN4_H P11 IN4_V P12 VCC3 P13 H_PH P14 V_PH P15 YG_OUT P16 YG_IN P17 CLP_SW P18 IREF P19 NC P20 EXTCLK/XTAL P21 NC P22 SELH_OUT P23 SELV_OUT P24 GND2 P25 SELCR_OUT P26 SELCB_OUT P27 SELY_OUT P28 VCC2 P29 CLP_CR P30 SCL P31 SDA P32 ADDRESS P33 IN1_1 P34 IN1_2 P35 IN1_3 P36 IN1_H/L1 P37 IN1_V/L2 P38 IN1_L3 P39 IN1_SW P40 VCC1 P41 IN2_1 P42 IN2_2 P43 IN2_3 P44 IN2_H/L1 P45 IN2_V/L2 P46 IN2_L3 P47 IN2_SW P48 GND1 DTC114EUA-T106 Q205 INV_SW 1/16W CHIP 10k R257 2SA1576A-T106-QR Q206 SLICE 2SA1576A-T106-QR Q207 SLICE 1/16W CHIP 4.7k R206 1/16W CHIP 47 R207 1/16W CHIP 47k R208 1/16W CHIP 47k R209 1/16W CHIP 10 R210 1/16W CHIP 1k R230 2SC4081T106R Q201 BUFFER 10V 0.1 B C201 1/16W CHIP 47k R231 1/16W CHIP 47k R232 2SC4081T106R Q209 BUFFER 1/16W CHIP 1k R205 1/16W CHIP 10 R203 1/16W CHIP 47k R223 1/16W CHIP 47k R222 14 13 12 11 10 9 8 7 1 2 3 4 5 6 SN74LV00APWR IC204 NAND 1A 1B 1Y 2A 2B 2Y GND 3Y 3A 3B 4Y 4A 4B VCC 10V 0.1 B C239 R267 XX 4MHz X201 2012 VPL-CS7 VPL-ES2 C222 XX 1 6.3V B R216 XX 0 CHIP R217 XX 0 CHIP 10V 4.7 F C242 1/16W CHIP 470 R271 1/16W CHIP 470 R272 2012 10V 4.7 F C243 Q208 BUFFER XX XX R242 CHIP R243 0 XX R233 XX R238 CHIP 0 R245 XX R226 XX R227 CHIP 0 R236 CHIP R266 0 3216 10V 22 F C230 *C222 1608 10V 0.47 B C224 1608 16V 0.22 B C223 SW0 SOG_B *R216 XX R273 XX R277 Q210 BUFFER XX *R217 XX R274 XX R276 XX R275 SDA_100K_1 SCL_100K_1 TO 10/10 TO 10/10 TO 8/10,9/10 TO 1/10,8/10 TO 1/10,8/10 TO 1/10 TO 8/10 TO 8/10 TO 8/10 TO 8/10,10/10 C (2/10) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com VPL-CS7/ES2 6-4 6-4 2 3 4 5 A B C D E F G H 1 C (3/10) C (3/10) C (3/10) 10V 0.1 B C361 PW_DVS 10V 0.1 B C343 5V-2 10V 0.1 B C312 10V 0.1 B C365 10V B C368 0.1 CHIP 0 R339 3216 10V 22 F C337 JL313 10V 0.1 B C326 CHIP XX R342 10V 0.1 B C367 10V 0.1 B C304 CHIP XX R343 10V 0.1 B C369 10V B C311 0.1 10V 0.1 B C350 10V 0.1 B C363 0uH FB303 10V 0.1 B C314 10V B C321 0.1 1/16W CHIP 100 R317 1/16W CHIP 22 R328 SCL_PW 1/16W CHIP 1k R312 10V 0.1 B C322 10V B C325 0.1 PW 1/16W CHIP XX R313 1/16W CHIP 10k R341 10V B C317 0.1 10V B C319 0.1 3216 10V 22 F C359 GBUS SDA_PW 0uH FB306 A1 B1 A2 B2 A3 B3 A4 A5 A6 B4 B5 B6 A7 B7 A8 B8 A9 B9 A10 B10 A11 B11 A12 B12 A13 B13 A14 B14 A15 B15 A16 B16 A17 B17 A18 B18 A19 B19 A20 B20 A21 B21 A22 B23 B27 B24 B25 A28 B28 A29 B29 A24 A25 A26 A23 A30 B30 B26 A27 A32 A33 A31 B31 B33 B32 A35 B35 B22 A34 B34 CN302 FOR_EMULATOR XX GND GND GND GND A15 A13 A11 A9 A7 A5 A3 A1 GND GND GND D3.3V D3.3V D3.3V D3.3V GND GND ROMWEN ROMWEN CS0 CS1 RESETN NM1 FCEN BOOTWE VPPEN D14 D12 D10 D8 D6 D4 D2 D0 NC 5V 5V GND GND GND D15 D13 D11 D9 D7 D5 D3 D1 NC 5V 5V A19 A18 A17 A16 A14 A12 A10 A8 A6 A4 A2 A0 BHENN ROMOEN ROMOEN 1/16W CHIP 22 R345 PWFMBSY PW_OSD_EN 0uH FB301 10V 0.1 B C318 10V 0.1 B C324 1/16W CHIP 22 R346 3216 10V 22 F C301 CHIP 0 R337 10V 0.1 B C316 1/16W CHIP 4.7k R316 50V 12p CH C339 PW_OUT1 JL321 1/16W CHIP 2.2k R344 X301 16.384MHz X TAL CHIP XX R338 10V B C364 0.1 1/16W CHIP 22 R347 1/16W CHIP 4.7k R318 1005 10V 0.1 B C356 50V 12p CH C341 10V B C327 0.1 10V 0.1 B C310 10V 0.1 B C308 10V 0.1 B C306 10V 0.1 B C302 10V 0.1 B C373 10V B C370 0.1 10V 0.1 B C371 10V B C372 0.1 10V 0.1 B C351 10V 0.1 B C357 10V 0.1 B C353 10V 0.1 B C355 10V 0.1 B C352 10V 0.1 B C354 10V 0.1 B C349 10V 0.1 B C348 0uH FB305 14 13 12 11 10 9 8 7 1 2 3 4 5 6 TC74LCX125FT(EL) IC302 SELECT_BUFF A0 B0 O0 A1 B1 O1 GND O3 P3 A3 O2 B2 A2 VCC 1005 10V 0.1 B C345 1/16W CHIP 10k R307 1/16W CHIP 100 R315 10V 0.1 B C344 CHIP R340 XX 2.5V 3216 10V 22 F C358 3.3V-2 3.3V-2 C332 10V 0.1 B C340 10V 0.1 B 1/16W CHIP 10k R310 C342 1005 10V B 0.1 1/16W CHIP XX R332 1/16W CHIP 10k R333 1.55V 0uH FB302 1.55V 3216 10V 22 F C347 3.3V-2 3.3V-2 3.3V-2 3.3V-2 3.3V-2 CHIP XX R324 CHIP R325 10k 1/16W CHIP XX R326 CHIP R327 10k 1/16W CHIP XX R319 CHIP 0 R330 SN74LV02APWR IC305 5/5 14 VCC 7 GND SN74LV02APWR IC305 2/5 NOR 5 4 6 SN74LV02APWR IC305 1/5 NOR 2 1 3 SN74LV02APWR IC305 4/5 NOR 11 13 12 SN74LV02APWR IC305 3/5 NOR 8 10 9 5 4 3 2 1 S-80928CNMC-G8Y-T2 IC303 RESET OUT VDD VSS NC CD CHIP XX R348 CHIP 0 R349 PW_OUT2 JL322 JL327 JL328 JL329 JL330 CHIP 0 R350 JL332 10V 0.1 B C379 1/16W CHIP 10k R354 16.384MHz X302 50V 12p CH C380 50V 12p CH C381 1/16W CHIP 1k R314 1/16W CHIP XX R355 CHIP 0 R356 SIGCH_FLAG JL305 JL306 RST_COM XX R301 8 7 6 5 4 3 2 1 CY25023SZC-1T IC304 SPREAD_SPECTRUM X1/CLK VDD PD#/OE VSS SSCK REFCLK SSON XOUT DISPLAY PORT PW168A-05VL IC301 4/5 SCAN_CONV DCLK DVS DHS DEN DRE0 DRE1 DRE2 DRE3 DRE4 DRE5 DRE6 DRE7 DGE0 DGE1 DGE2 DGE3 DGE4 DGE5 DGE6 DGE7 DBE0 DBE1 DBE2 DBE3 DBE4 DBE5 DBE6 DBE7 DRO0 DRO1 DRO2 DRO3 DRO4 DRO5 DRO6 DRO7 DGO0 DGO1 DGO2 DGO3 DGO4 DGO5 DGO6 DGO7 DBO0 DBO1 DBO2 DBO3 DBO4 DBO5 DBO6 DBO7 J17 C20 D18 N19 V19 Y20 R16 U19 R18 W20 V20 U20 T19 T20 R19 R20 M18 P18 P19 P20 M17 N20 M20 L17 M19 K17 L19 L20 K19 K20 K18 J20 J18 J19 H20 H19 H18 H17 G20 G19 G18 F20 F19 F18 E20 E19 E18 F17 D20 D19 D16 D17 MISC PW168A-05VL IC301 3/5 SCAN_CONV RESET Y11 MCKEXT E5 XI A3 RXD Y12 XO C5 TXD V12 IRRCVR0 V11 IRRCVR1 W11 PORTA0 V13 A0 U4 DCKEXT D6 PORTA1 W13 PORTA2 Y13 PORTA3 Y14 PORTA4 W14 PORTA5 Y15 PORTA6 W15 PORTA7 V15 PORTB0 R17 PORTB1 W18 PORTB2 V18 PORTB3 Y18 PORTB4 U18 PORTB5 Y19 PORTB6 W19 PORTB7 T18 PORTC0 T17 PORTC1 V16 PORTC2 W16 PORTC3 Y16 PORTC4 V17 PORTC5 U17 PORTC6 W17 PORTC7 Y17 CPUTMS P1 CPUTCK Y2 CPUTDI M4 CPUTDO N3 MODE0 U16 MODE1 N4 MODE2 T5 MODE3 P2 ADR24B U15 A1 T4 A2 V3 A3 U3 A4 Y1 A5 W2 A6 T3 A7 V2 A8 U2 A9 W1 A10 R4 A11 V1 A12 P4 A13 R3 A14 T2 A15 U1 A16 T1 A17 R2 A18 R1 A19 P3 D0 V10 D1 Y10 D2 Y9 D3 W9 D4 V9 D5 Y8 D6 W8 D7 V8 D8 W7 D9 U8 D10 V7 D11 W6 D12 Y6 D13 V6 D14 U7 D15 U6 RD W3 WR Y3 BHEN W12 ROMOE V5 ROMWE W4 RAMOE W5 RAMWE Y5 CS0 V4 CS1 Y4 EXTINT U10 NMI W10 DNC1 B20 DNC2 C19 DNC3 V14 VIDEO PORT PW168A-05VL IC301 2/5 SCAN_CONV VCLK E1 VPEN N2 VHS F3 VR0 E2 FIELD D1 VVS E3 VR1 F1 VR2 F2 VR3 G3 VR4 G2 VR5 H3 VR6 H2 VR7 G1 VG0 J4 VG1 H1 VG2 J3 VG3 J2 VG4 J1 VG5 K3 VG6 K2 VG7 K1 VB0 L2 VB1 L1 VB2 L3 VB3 L4 VB4 M3 VB5 M1 VB6 N1 VB7 M2 POWER AND GROUND PW168A-05VL IC301 5/5 SCAN_CONV VDD1.5 H5 GND A1 GND Y7 GND B2 GND B3 GND N18 GND L18 GND D4 GND G4 GND H4 GND K4 GND U12 GND U14 GND P17 GND N17 GND G17 GND D15 GND D13 GND D12 GND D11 GND D9 GND D8 GND D5 GND R5 GND H8 GND J8 GND K8 GND L8 GND M8 GND N8 GND N9 GND N10 GND N11 GND N12 GND N13 GND M13 GND L13 GND K13 GND J13 GND H13 GND H12 GND H11 GND H10 GND H9 GND J9 GND K9 GND L9 GND M9 GND M10 GND M11 GND M12 GND L12 GND K12 GND J12 GND J11 GND J10 GND K10 GND L10 GND L11 GND K11 VDD1.5 J5 VDD1.5 K5 VDD1.5 L5 VDD1.5 N5 VDD1.5 P5 VDD1.5 T6 VDD1.5 T7 VDD1.5 T9 VDD1.5 T10 VDD1.5 T11 VDD1.5 T12 VDD1.5 T13 VDD1.5 T14 VDD1.5 T15 VDD1.5 P16 VDD1.5 N16 VDD1.5 K16 VDD1.5 H16 VDD1.5 F16 VDD1.5 E15 VDD1.5 E14 VDD1.5 E13 VDD1.5 E12 VDD1.5 E11 VDD1.5 E10 VDD1.5 E9 VDD1.5 E7 VDD1.5 N6 VDD1.5 P6 VDD1.5 R13 VDD1.5 R14 VDD1.5 R15 VDD1.5 P15 VDD1.5 N15 VPP1 B4 VPP2 C4 VCC2.5 A2 VCC2.5 U5 VCC2.5 U9 VCC2.5 U11 VCC2.5 U13 VCC2.5 T16 VIO3.3 F5 VIO3.3 G5 VIO3.3 M5 VIO3.3 T8 VIO3.3 M16 VIO3.3 L16 VIO3.3 J16 VIO3.3 G16 VIO3.3 E8 VIO3.3 E6 VIO3.3 F6 VIO3.3 G6 VIO3.3 R6 VIO3.3 R7 VIO3.3 R8 VIO3.3 G15 VIO3.3 F15 VIO3.3 F14 VIO3.3 F7 1 2 3 4 5 6 7 42 43 44 45 46 47 48 41 40 39 38 37 36 35 34 33 16 15 14 13 12 11 10 9 8 32 31 30 29 28 27 26 25 17 18 19 20 21 22 23 24 MX29LV800ATTC-70G-751PW103 IC306 FLASH_ROM A15 A14 A13 A12 A11 A10 A9 A8 NC NC WE RESET NC NC RY/BY A18 A17 A7 A6 A5 A4 A3 A2 A1 A0 CE GND OE Q0 Q8 Q1 Q9 Q2 Q10 Q3 Q11 VCC Q4 Q12 Q5 Q13 Q6 Q14 Q7 Q15/A-1 GND BYTE A16 1/10W RN-CP 330 R360 GRAPHIC PORT PW168A-05VL IC301 1/5 SCAN_CONV GCLK A10 GVS A9 GPEN B9 GRE0 E4 GSOG B10 GRE1 C3 GRE2 B1 GRE3 F4 GRE4 C2 GRE5 C1 GRE6 D3 GRE7 D2 GGE0 C11 GGE1 B12 GGE2 B11 GGE3 A8 GGE4 B8 GGE5 C8 GGE6 A7 GGE7 B7 GBE0 B18 GBE1 A20 GBE2 B17 GBE3 A19 GBE4 B16 GBE5 A17 GBE6 A16 GBE7 A15 GRO0 A6 GRO1 C7 GRO2 B6 GRO3 A5 GRO4 D7 GRO5 B5 GRO6 C6 GRO7 A4 GGO0 C13 GGO1 B15 GGO2 A14 GGO3 B14 GGO4 A13 GGO5 C12 GGO6 B13 GGO7 A12 GBO0 C18 GBO1 E17 GBO2 C17 GBO3 B19 GBO4 E16 GBO5 C16 GBO6 C15 GBO7 D14 GFBK A11 GREF D10 GBLKSPL C14 GCOAST A18 GHSFOUT C9 GHS C10 0uH FB304 ROMWEN PW_D[2] PW_D[14] PW_D[3] PW_D[6] PW_D[4] PW_D[13] PW_D[5] PW_D[5] PW_D[6] PW_DHS VPPEN PW_D[12] PW_D[7] CS0 PW_D[8] PW_D[8] PW_D[9] PW_D[1] ROMWEN ROMWEN PW_D[10] PW_D[9] PW_D[11] PW_D[2] PW_D[15] PW_D[12] ROMOEN PW_D[10] PW_D[13] BHENN PW_OSD_EN PW_D[14] PW_D[0] PW_D[15] ROMOEN CS1 RESETN PW_D[11] FCEN PW_D[4] BOOTWE PW_D[7] PW_DCLK BOOTWE CS1 CS0 VPPEN ROMWEN ROMOEN PW_D[0] BHENN PW_D[1] GRE[0] GRE[1] GRE[2] GRE[3] GRE[4] GRE[5] GRE[6] GRE[7] GGE[0] GGE[1] GGE[2] GGE[3] GGE[4] GGE[5] GGE[6] GGE[7] GBE[0] GBE[1] GBE[2] GBE[3] GBE[4] GBE[5] GBE[6] GBE[7] PW_A[0] PW_A[1] PW_A[2] PW_A[3] PW_A[4] PW_A[5] PW_A[6] PW_A[7] PW_A[8] PW_A[9] PW_A[10] PW_A[11] PW_A[12] PW_A[13] PW_A[14] PW_A[15] PW_A[16] PW_A[17] PW_A[18] PW_A[19] PW_D[0] PW_D[1] PW_D[2] PW_D[3] PW_D[4] PW_D[5] PW_D[6] PW_D[7] PW_D[8] PW_D[9] PW_D[10] PW_D[11] PW_D[12] PW_D[13] PW_D[14] PW_D[15] PW_A[1] PW_A[2] PW_A[3] PW_A[4] PW_A[5] PW_A[6] PW_A[7] PW_A[8] PW_A[9] PW_A[10] PW_A[11] PW_A[12] PW_A[13] PW_A[14] PW_A[15] PW_A[16] PW_A[17] PW_A[18] PW_A[19] FCEN FCEN PW_A[4] PW_A[10] PW_A[14] PW_A[2] PW_A[9] PW_A[17] PW_A[0] PW_A[1] PW_A[15] PW_A[19] PW_A[18] PW_A[6] PW_A[3] PW_A[8] PW_A[13] PW_A[12] PW_A[5] PW_A[16] PW_A[7] PW_A[11] P-RX P-TX TXD_PW RXD_PW PIC_MUTE P-EXTSW RESETN PW_DVS INTERLACE GCLK GVS GHS GCOAST GFBK PW_D[3] NMI PW_DRE[2] PW_DRE[3] PW_DRE[4] PW_DRE[5] PW_DRE[6] PW_DRE[7] PW_DRE[8] PW_DRE[9] PW_DGE[2] PW_DGE[3] PW_DGE[4] PW_DGE[5] PW_DGE[6] PW_DGE[7] PW_DGE[8] PW_DGE[9] PW_DBE[2] PW_DBE[3] PW_DBE[4] PW_DBE[5] PW_DBE[6] PW_DBE[7] PW_DBE[8] PW_DBE[9] PW_DBE[0] PW_DBE[1] PW_DGE[0] PW_DGE[1] PW_DRE[0] PW_DRE[1] NMI TO 8/10 TO 8/10 TO 4/10 TO 1/10 TO 8/10 TO 8/10 TO 4/10 TO 8/10 TO 4/10 TO 1/10 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com VPL-CS7/ES2 2 3 4 5 1 6-5 6-5 A B C D E F G H C (4/10) C (4/10) C (4/10) 10V 0.1 B C443 10V 0.1 B C442 47 RB409 1 2 3 4 5 6 7 8 47 RB410 1 2 3 4 5 6 7 8 47 RB408 1 2 3 4 5 6 7 8 47 RB407 1 2 3 4 5 6 7 8 RGT 1/16W CHIP 47 R404 1/16W CHIP 47 R403 10V 0.1 B C439 1/16W CHIP 47k R434 1/16W CHIP 47 R424 1/16W CHIP 47 R423 1/16W CHIP 47 R422 MCLK_R MCLK_G MCLK_B 20 19 18 17 16 15 14 13 12 11 1 2 3 4 5 6 7 8 9 10 SN74AHCT541PWR IC409 BUFFER G1 A1 A2 A3 A4 A5 A6 A7 A8 GND Y8 Y7 Y6 Y5 Y4 Y3 Y2 Y1 G2 VCC 10V 0.1 B C444 10V 0.1 B C445 47 RB413 47 RB412 47 RB411 8 7 6 5 4 3 2 1 TC7WH125FK(TE85R) IC402 BUFFER G1 A1 Y2 GND A2 Y1 G2 VCC PW_OSD_EN 10V 0.1 B C437 1/16W CHIP 2.2k R429 DA_R 22 RB402 22 RB403 22 RB404 22 RB405 1 2 3 4 5 6 7 8 22 RB406 1 2 3 4 5 6 7 8 DA_G DA_B TG_G TG 5 4 3 2 1 S-80928CNMC-G8Y-T2 IC403 RESET OUT VDD VSS NC CD 5 4 3 2 1 S-80928CNMC-G8Y-T2 IC404 RESET OUT VDD VSS NC CD PW_OUT1 I2C_400K 10V 0.1 B C401 DWN 10V 0.1 B C421 10V B C422 0.1 10V B C420 0.1 10V 0.1 B C419 10V B C418 0.1 10V 0.1 B C416 10V B C415 0.1 10V 0.1 B C414 10V B C413 0.1 10V 0.1 B C412 10V B C411 0.1 10V 0.1 B C410 10V 0.1 B C407 10V B C406 0.1 10V 0.1 B C405 10V 0.1 B C433 10V B C432 0.1 10V 0.1 B C431 10V B C430 0.1 10V 0.1 B C428 10V B C427 0.1 10V 0.1 B C426 10V 0.1 B C435 1.8V 1/16W CHIP 10k R401 1/16W CHIP 10k R402 10V 0.1 B C417 10V B C409 0.1 10V 0.1 B C408 10V 0.1 B C429 GCFB_B GCFB_G GCFB_R 1/16W CHIP 4.7k R432 1/16W CHIP 4.7k R435 1/16W CHIP 4.7k R436 1/16W CHIP 10k R430 1/16W CHIP 4.7k R440 1/16W CHIP 4.7k R441 1/16W CHIP 47 R443 1/16W CHIP 47 R444 HN1B01FU-TE85R Q404 BUFF 1/16W CHIP 1k R437 20 19 18 17 16 15 14 13 12 11 1 2 3 4 5 6 7 8 9 10 TC74VHCT540AFT(EL) IC410 INVERT BUFF G1 A1 A2 A3 A4 A5 A6 A7 A8 GND Y8 Y7 Y6 Y5 Y4 Y3 Y2 Y1 G2 VCC TG_B TG_R 47 RB414 20 19 18 17 16 15 14 13 12 11 1 2 3 4 5 6 7 8 9 10 SN74AHCT541PWR IC408 BUFFER G1 A1 A2 A3 A4 A5 A6 A7 A8 GND Y8 Y7 Y6 Y5 Y4 Y3 Y2 Y1 G2 VCC 20 19 18 17 16 15 14 13 12 11 1 2 3 4 5 6 7 8 9 10 SN74AHCT541PWR IC407 BUFFER G1 A1 A2 A3 A4 A5 A6 A7 A8 GND Y8 Y7 Y6 Y5 Y4 Y3 Y2 Y1 G2 VCC RGT_3.3 16V 0.01 B C404 10V 0.1 B C438 1/16W CHIP 100 R428 6.3V 47 C436 0uH FB401 1/16W CHIP 22 R414 1/16W CHIP 22 R416 3.3V-2 3.3V-2 3.3V-2 3.3V-2 1uH L401 5V-2 5V-2 5V-2 5V-2 XX R446 CHIP R447 0 PW_OUT2 JL442 22 RB401 22 RB415 RGTX_3.3 RGTX 8 7 6 5 4 3 2 1 HN58X24256FPIZ IC406 EEP_ROM A0 A1 A2 VSS SDA SCL WP VCC CXD3536R IC401 1/4 3D GAMMA_TG RIN9 P1 RIN8 P2 RIN7 P3 RIN6 P5 RIN5 P6 RIN4 P7 RIN3 P10 RIN2 P11 RIN1 P12 RIN0 P13 GIN9 P16 GIN8 P17 GIN7 P18 GIN6 P19 GIN5 P22 GIN4 P23 GIN3 P24 GIN2 P25 GIN1 P26 BIN9 P31 BIN8 P32 BIN7 P35 BIN6 P36 BIN5 P37 BIN2 P40 BIN4 P38 BIN3 P39 ROUT6 P130 ROUT8 P132 BOUT1 P91 BOUT7 P100 GOUT2 P109 GOUT8 P117 ROUT1 P122 ROUT4 P127 ROUT9 P133 BOUT3 P94 GOUT1 P108 GOUT9 P118 GOUT4 P111 GOUT7 P114 GOUT5 P112 ROUT0 P121 ROUT3 P126 ROUT2 P123 ROUT5 P128 BOUT2 P93 BOUT5 P98 BOUT6 P99 GOUT3 P110 GOUT6 P113 ROUT7 P131 BOUT4 P95 NC P88 BOUT0 P90 NC P89 GND P14 GND P15 GIN0 P27 GND P28 GND P29 BIN1 P41 BIN0 P42 GND P43 GND P44 ROSD1 P60 ROSD0 P59 GOSD1 P62 GOSD0 P61 BOSD1 P65 BOSD0 P64 YS P56 YM P55 NC P120 NC P119 GOUT0 P107 NC P104 NC P103 BOUT8 P101 BOUT9 P102 IC401 CXD3536R 3/4 3D GAMMA_TG VDDA P45 VDD P4 VSS P9 VSSA P46 VDD P30 VDD P58 VDD P78 VDD P92 VDD P129 VDD P138 VDD P168 VDE P8 VDE P20 VDE P33 VDE P54 VDE P63 VDE P71 VDE P75 VDE P81 VDE P86 VDE P96 VDE P105 VDE P115 VDE P124 VDE P134 VDE P145 VDE P155 VDE P163 VDE P171 VSS P21 VSS P34 VSS P57 VSS P70 VSS P76 VSS P82 VSS P87 VSS P97 VSS P106 VSS P116 VSS P125 VSS P135 VSS P148 VSS P160 VSS P172 IC401 4/4 3D GAMMA_TG CXD3536R SOUT1 P173 SHST P139 HST P164 PST P167 HCK1 P149 HCK2 P150 DCK1 P151 DCK2 P152 DCK3 P153 DCK4 P154 DCK5 P156 DCK6 P157 FRP P158 XFRP P140 RGT P170 XRGT P141 ENB P144 PCG P165 PRG P166 VST P136 VCK P137 DWN P169 HD1 P159 HD2 P161 HD3 P162 PO1 P146 PO2 P147 SOUT2 P174 SOUT3 P175 CTRL P176 CLP P142 CLR P143 IC401 2/4 3D GAMMA_TG CXD3536R CLKSEL P72 CLKOUT1 P83 CLKOUT2 P84 CLKOUT3 P85 PLLDIV P47 PLLSTB P48 TRST P49 TEST1 P50 TEST2 P51 RSCL P80 RSDA P79 CLKPOL P74 CLKC P73 HDIN P66 VDIN P67 XCLR2 P52 XCLR3 P53 HSEL P69 HSCL P68 HSDA P77 JL401 JL402 2SC4081T106R Q403 SW 1/16W CHIP 1k R433 10V 0.1 B C402 10V 0.1 B C441 0uH FB402 3216 10V 10 F C403 3216 10V 10 F C423 JL427 HCK2_R HCK1_R HCK2_G HCK2_B HCK1_B HCK1_G FRP PCG VCK VST HST ENB PRG PW_DRE[8] PW_DRE[7] PW_DRE[6] PW_DRE[5] PW_DRE[4] PW_DGE[9] PW_DGE[8] PW_DGE[7] PW_DGE[6] PW_DGE[5] PW_DBE[4] PW_DBE[5] PW_DBE[6] PW_DBE[7] PW_DBE[8] PW_DBE[9] PW_DHS PW_DVS R[9] R[7] R[6] R[5] R[4] R[3] R[2] G[7] G[6] G[5] G[4] G[0] G[1] G[2] G[3] B[7] B[6] B[5] B[4] B[3] B[2] B[1] B[0] LCDHST LCDHCK1 LCDHCK2 RGT_3.3 RGTX_3.3 LCDENB LCDPCG LCDVCK LCDDWN LCDCLR LCDHCK1 LCDENB LCDHST LCDVST LCDVCK LCDPCG DCK1 DCK2 DCK3 DCK4 LCDFRP LCDPRG LCDVST LCDHCK2 PW_DCLK RGT_3.3 DCK1X_B CLR DCK1X_G DCK2X_G DCK5 DCK6 DCK2X_R DCK1X_R PW_DRE[9] R[8] B[9] B[8] PW_DRE[3] PW_DRE[2] PW_DGE[4] PW_DGE[2] PW_DBE[3] PW_DGE[3] PW_DBE[2] LCDDWN PW_DRE[1] PW_DRE[0] PW_DGE[1] PW_DGE[0] PW_DBE[0] PW_DBE[1] G[9] G[8] R[1] R[0] LCDFRP LCDPRG RGTX_3.3 SDA_400K SCL_400K LCDCLR DCK2_B DCK1_B DCK2_G DCK1_G DCK2_R DCK1 DCK1 DCK2 DCK2 DCK3 DCK3 DCK4 DCK4 DCK5 DCK5 DCK6 DCK6 DCK2X_B DCK1_R TO 3/10 TO 3/10 TO 8/10 TO 6/10 TO 5/10 TO 7/10 TO 3/10 TO 6/10 TO 5/10 TO 7/10 TO 7/10 TO 5/10 TO 6/10 TO 6/10 TO 5/10 TO 7/10 TO 5/10,6/10,7/10 TO 5/10 TO 5/10 TO 6/10,7/10 TO 6/10,7/10 TO 5/10,6/10,7/10 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com VPL-CS7/ES2 6-6 6-6 2 3 4 5 A B C D E F G H 1 C (5/10) C (5/10) 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 20 19 21 22 23 24 25 26 27 28 29 30 31 32 32P CN501 N.C. VCOMR PSIG VSSGR VSIG1 VSIG2 VSIG3 VSIG4 VSIG5 VSIG6 HVDD DCK2 DCK2X DCK1X DCK1 HCK HCKX RGT HST HVSS VSSGL VVSS ENB VCK VST DWN CLR PCG SOUT VVDD VCOML GCFB 1/16W CHIP 2.2k R508 1/16W CHIP 100 R506 HN1B01FU-TE85R Q502 BUFFER HN1B01FU-TE85R Q501 BUFFER 1/16W CHIP 10 R509 1/16W CHIP 2.2k R507 1/16W CHIP 10 R510 1608 25V 0.1 F C510 3LINESBUS TG TG_G 1uH L504 1uH L503 1/16W CHIP 10k R505 RGTX_3.3 MCLK_G 25V 47 C511 25V 47 C507 25V 47 C506 1608 25V 0.1 F C509 1608 25V 0.1 F C504 1608 25V 0.1 F C513 1608 25V 0.1 F C512 1608 25V 0.1 F C508 10V 0.1 B C502 GCFB_G DWN 1/16W CHIP 47 R512 22 RB501 1 2 3 4 5 6 7 8 15.5V 13.5V 15.5V 15.5V DA_G 25V 47 C514 3216 25V 1 B C515 3216 25V 1 B C516 1/16W CHIP R502 10k 1/16W CHIP 10k R504 1/16W CHIP R501 XX 1/16W CHIP 10k R503 RGTX 17V 13.5V 1/16W CHIP 47k R514 XX C517 1005 16V 0.01 B C518 15.5V 25V 47 C520 1/16W RN-CP 1k R516 1/16W RN-CP 4.7k R517 3.3V-2 JL502 PDRV_SENB PDRV_SCLK PDRV_SDAT 8 7 6 5 4 3 2 1 TC7WH34FU(TE12R) IC504 BUS BUFF 1005 10V 0.1 B C522 3.3V-2 JL503 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 CXA7005R-T4 IC501 LCD_DRIVER P1 DGND P2 DGND P3 SENB P4 SCLK P5 SDAT P6 ADDR0 P7 ADDR1 P8 AGND P9 AGND P10 REFIN P11 VCC P12 SIG_C P13 VCOM_OUT P14 PVCC P15 SIG_OUT6 P16 SIG_OUT5 P17 SIG_OUT4 P18 PGND P19 PGND P20 SIG_OUT3 P21 SIG_OUT2 P22 SIG_OUT1 P23 PVCC P24 SIF_OUT P25 VCC P26 AGND P27 AGND P28 AGND P29 FRINV P30 STATUS P31 DIRC P32 PRG P33 FRP P34 CLK P35 VDD P36 DGND P37 D_IN9 P38 D_IN8 P39 D_IN7 P40 D_IN6 P41 D_IN5 P42 D_IN4 P43 D_IN3 P44 D_IN2 P45 D_IN1 P46 D_IN0 P47 DGND P48 DGND 1 2 3 4 5 PQ20WZ1UJ00H IC503 0uH FB501 3216 10V 22 F C501 25V 47 C503 1/16W CHIP 4.7k R515 1 2 3 4 5 BA00ASFP-E2 IC502 HST ENB VCK VST PCG DCK2_G DCK2X_G DCK1X_G DCK1_G HCK1_G HCK2_G FRP PRG SENB SCLK SDAT VID_G[2] VID_G[3] VID_G[4] VID_G[5] VID_G[6] VCOM_OUT_G G[0] G[1] G[2] G[3] G[4] G[5] G[6] G[7] G[8] G[9] VCOM_OUT_G VID_G[1] VID_G[2] VID_G[3] VID_G[4] VID_G[5] VID_G[6] CLR SENB SDAT SCLK VID_G[1] TO 4/10 TO 4/10 TO 4/10 TO 8/10 TO 6/10,7/10 TO 4/10 TO 4/10,6/10,7/10 TO 4/10,6/10,7/10 TO 4/10 TO 4/10 C (5/10) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com VPL-CS7/ES2 2 3 4 5 1 6-7 6-7 A B C D E F G H C (6/10) C (6/10) 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 20 19 21 22 23 24 25 26 27 28 29 30 31 32 32P CN601 N.C. VCOMR PSIG VSSGR VSIG1 VSIG2 VSIG3 VSIG4 VSIG5 VSIG6 HVDD DCK2 DCK2X DCK1X DCK1 HCK HCKX RGT HST HVSS VSSGL VVSS ENB VCK VST DWN CLR PCG SOUT VVDD VCOML GCFB 1/16W CHIP 2.2k R608 1/16W CHIP 100 R606 HN1B01FU-TE85R Q602 BUFFER HN1B01FU-TE85R Q601 BUFFER 1/16W CHIP 10 R609 1/16W CHIP 2.2k R607 1/16W CHIP 10 R610 1608 25V 0.1 F C610 3LINESBUS TG TG_R 1uH L604 1uH L603 1/16W CHIP 10k R605 RGT_3.3 MCLK_R 25V 47 C611 25V 47 C607 25V 47 C606 1608 25V 0.1 F C609 1608 25V 0.1 F C604 1608 25V 0.1 F C614 1608 25V 0.1 F C612 1608 25V 0.1 F C608 GCFB_R DWN 1/16W CHIP 47 R612 22 RB601 1 2 3 4 5 6 7 8 15.5V 13.5V 15.5V 15.5V DA_R 25V 47 C615 3216 25V 1 B C613 3216 25V 1 B C616 1/16W CHIP R602 10k 1/16W CHIP R604 10k 1/16W CHIP 10k R601 1/16W CHIP R603 XX RGT 10V 0.1 B C602 3.3V-2 JL602 JL603 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 CXA7005R-T4 IC601 LCD_DRIVER P1 DGND P2 DGND P3 SENB P4 SCLK P5 SDAT P6 ADDR0 P7 ADDR1 P8 AGND P9 AGND P10 REFIN P11 VCC P12 SIG_C P13 VCOM_OUT P14 PVCC P15 SIG_OUT6 P16 SIG_OUT5 P17 SIG_OUT4 P18 PGND P19 PGND P20 SIG_OUT3 P21 SIG_OUT2 P22 SIG_OUT1 P23 PVCC P24 SID_OUT P25 VCC P26 AGND P27 AGND P28 AGND P29 FRINV P30 STATUS P31 DIRC P32 PRG P33 FRP P34 CLK P35 VDD P36 DGND P37 D_IN9 P38 D_IN8 P39 D_IN7 P40 D_IN6 P41 D_IN5 P42 D_IN4 P43 D_IN3 P44 D_IN2 P45 D_IN1 P46 D_IN0 P47 DGND P48 DGND 0uH FB601 3216 10V 22 F C601 R[0] R[1] R[2] R[3] R[4] R[5] R[6] R[7] R[8] R[9] VCOM_OUT_R HST ENB VCK VST PCG DCK2_R DCK2X_R DCK1X_R DCK1_R HCK1_R HCK2_R FRP PRG SENB SCLK SDAT VID_R[1] VID_R[3] VID_R[5] VID_R[6] VID_R[1] VID_R[2] VID_R[3] VID_R[4] VID_R[5] VID_R[6] VCOM_OUT_R CLR VID_R[4] VID_R[2] TO 4/10 TO 4/10,7/10 TO 4/10 TO 5/10,7/10 TO 4/10 TO 4/10,5/10,7/10 TO 4/10,5/10,7/10 TO 4/10,7/10 TO 4/10 C (6/10) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com VPL-CS7/ES2 6-8 6-8 2 3 4 5 A B C D E F G H 1 C (7/10) C (7/10) 10V 0.1 B C652 3216 25V 1 B C665 TG_B 25V 47 C657 3LINESBUS 1/16W CHIP 10 R660 25V 47 C661 3216 25V 1 B C666 1608 25V 0.1 F C662 1uH L653 HN1B01FU-TE85R Q651 BUFFER 1/16W CHIP 2.2k R658 1608 25V 0.1 F C660 1uH L654 1/16W CHIP R653 10k 1608 25V 0.1 F C663 MCLK_B 22 RB651 1 2 3 4 5 6 7 8 1/16W CHIP 2.2k R657 DA_B 25V 47 C656 1/16W CHIP R654 XX TG RGT_3.3 15.5V 1/16W CHIP 100 R656 R652 1/16W CHIP 10k 15.5V 1608 25V 0.1 F C659 1/16W CHIP 10k R655 25V 47 C664 GCFB_B 13.5V 1/16W CHIP 10 R659 1608 25V 0.1 F C655 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 20 19 21 22 23 24 25 26 27 28 29 30 31 32 32P CN651 N.C. VCOMR PSIG VSSGR VSIG1 VSIG2 VSIG3 VSIG4 VSIG5 VSIG6 HVDD DCK2 DCK2X DCK1X DCK1 HCK HCKX RGT HST HVSS VSSGL VVSS ENB VCK VST DWN CLR PCG SOUT VVDD VCOML GCFB DWN 1608 25V 0.1 F C658 1/16W CHIP R651 XX 15.5V 1/16W CHIP 47 R662 HN1B01FU-TE85R Q652 BUFFER RGT 3.3V-2 JL652 JL653 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 CXA7005R-T4 IC651 LCD_DRIVER P1 DGND P2 DGND P3 SENB P4 SCLK P5 SDAT P6 ADDR0 P7 ADDR1 P8 AGND P9 AGND P10 REFIN P11 VCC P12 SIG_C P13 VCOM_OUT P14 PVCC P15 SIG_OUT6 P16 SIG_OUT5 P17 SIG_OUT4 P18 PGND P19 PGND P20 SIG_OUT3 P21 SIG_OUT2 P22 SIG_OUT1 P23 PVCC P24 SID_OUT P25 VCC P26 AGND P27 AGND P28 AGND P29 FRINV P30 STATUS P31 DIRC P32 PRG P33 FRP P34 CLK P35 VDD P36 DGND P37 D_IN9 P38 D_IN8 P39 D_IN7 P40 D_IN6 P41 D_IN5 P42 D_IN4 P43 D_IN3 P44 D_IN2 P45 D_IN1 P46 D_IN0 P47 DGND P48 DGND 0uH FB651 3216 10V 22 F C651 B[1] VCOM_OUT_B B[4] VID_B[1] B[7] B[0] B[8] VID_B[6] SCLK VST DCK1_B HST VCOM_OUT_B ENB DCK1X_B VID_B[3] PRG B[3] VID_B[5] VID_B[3] B[6] HCK2_B HCK1_B VID_B[5] VID_B[1] FRP DCK2_B VCK DCK2X_B SENB B[2] VID_B[2] SDAT B[5] PCG VID_B[2] B[9] VID_B[4] VID_B[4] VID_B[6] CLR TO 4/10 TO 4/10,6/10 TO 4/10 TO 5/10,6/10 TO 4/10,5/10,6/10 TO 4/10 TO 4/10,5/10,6/10 TO 4/10,6/10 TO 4/10 C (7/10) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com VPL-CS7/ES2 2 3 4 5 1 6-9 6-9 A B C D E F G H C (8/10) C (8/10) 1/16W CHIP 10k R735 1/16W CHIP 10k R739 *R728 1/16W CHIP 220 R727 10V 0.1 B C713 16V 0.01 B C712 10V 0.1 B C708 16.384MHz X701 1/16W CHIP 10 R726 *R724 TILT+ PWFMBSY 1/16W CHIP 47k R729 1/16W CHIP 10k R725 16V 0.01 B C707 1/16W CHIP 47k R733 HN1B01FU-TE85R Q702 RES_SW 1/16W CHIP 1k R736 1608 6.3V 1 B C716 SCL_E SDA_E 1/16W CHIP 10k R748 1/16W CHIP 10k R749 1/16W CHIP 10k R751 1/16W CHIP 10k R752 10V 0.1 B C715 1/16W CHIP 10k R741 10V 0.1 B C714 1/16W CHIP 10k R737 1/16W CHIP R723 10k 10V 0.1 B C706 100 RB707 1/16W CHIP 10k R732 1/16W CHIP 2.2k R722 1/16W CHIP 2.2k R721 CHIP 0 R714 CHIP 0 R715 1/16W CHIP 47k R716 1/16W CHIP 2.2k R719 1/16W CHIP 2.2k R720 1/16W CHIP 4.7k R711 1/16W CHIP 4.7k R712 I2C_400K 10V 4.7 F C705 1/16W CHIP 10k R718 1/16W CHIP 10k R717 POS_DET PW_DVS CPU 1/16W CHIP 10k R750 V_POL H_POL VS HS TILT_Y TILT_X 1/16W CHIP R744 33k 1/16W CHIP R745 33k SCL_E SDA_E 6.3V 47 C702 5V-1 1 2 3 4 5 6 7 8 9 10 11 12 12P CN702 GND TXD RXD RES VIN MD0 MD1 MD2 P-TX P-RX P-EXTSW GND 100 RB701 1 2 3 4 5 6 7 8 5V-1 PW 1/16W RN-CP 4.7k R706 16V 0.01 B C703 D1 G2 S2 D2 G1 S1 SSM6N15FU(TE85R) Q701 LEVEL_CONV 1/16W CHIP 10k R709 1/16W CHIP 10k R710 3.3V-1 3.3V-1 3.3V-2 3.3V-2 3.3V-1 JL701 AU_MUTE I2C_100K CHIP R753 0 PC_DTV 5 4 3 2 1 S-80928CNMC-G8Y-T2 IC704 RESET OUT VDD VSS NC CD R755 XX 1/16W CHIP 10k R756 8 7 6 5 4 3 2 1 M24C64-WMN6T(B) IC705 EEP_ROM A0 A1 A2 VSS SDA SCL WP VCC 1/16W CHIP 100 R759 1/16W CHIP 100 R760 1/16W CHIP 100 R761 DDC_SW0 DDC_WE D1 G2 S2 D2 G1 S1 SSM6N15FU(TE85R) Q703 LEVEL_CONV 1/16W CHIP 10k R762 1/16W CHIP 10k R763 SDA_100K_2 SCL_100K_2 INTERLACE TILT- TILT_EN GVS GHS CHIP 0 R767 CHIP 0 R768 XX R769 XX R770 JL709 1/16W CHIP 100 R773 PDRV_SENB R774 1/16W CHIP 100 PDRV_SCLK 1/16W CHIP 100 R776 PDRV_SDAT JL711 D1 G2 S2 D2 G1 S1 SSM6N15FU(TE85R) Q704 LEVEL_CONV 1/16W CHIP 4.7k R778 1/16W CHIP 4.7k R779 5V-3 1/16W CHIP 100 R782 1/16W CHIP 100 R783 SIGCH_FLAG TP701 XX TP702 XX 1 2 3 4 5 5P CN703 SUB +5V RXD TXD GND EXT_SW 1/16W CHIP 47 R702 TH702 16V 0.01 B C717 1/16W RN-CP 4.7k R785 100 RB705 JL712 JL713 JL714 JL715 JL716 JL717 JL718 JL719 JL720 1/16W CHIP 100 R705 10V 0.1 B C727 10V 0.1 B C728 10V 0.1 B C729 RD3.9SB-T1 D709 PROTECT RD3.9SB-T1 D711 PROTECT D702 AND XX D703 AND XX MON_OUT_EN I O ADJ AIC1117A-33PYJTR IC701 3.3V_REG MA3J14700LSO D712 D1FS4A-TA D713 D1FS4A-TA D714 10V B C786 0.1 10V B C787 0.1 CHIP 47 R742 1/16W CHIP 47 R743 1/16W 1/16W CHIP 1k R730 10V 0.1 B C704 10V 0.1 C701 B CHIP 100 R784 1/16W 1/16W CHIP 1k R757 1/16W CHIP 1k R758 1005 10V 0.1 B C718 1005 10V 0.1 B C719 TA *R704 *R708 XX R731 1/16W CHIP 10k R734 HD64F2378VFQ34V IC703 MD2 P1 Vss P2 P80/(IRQ0)/EDREQ2 P3 Vcc P4 PC0/A0 P5 PC1/A1 P6 PC2/A2 P7 PC3/A3 P8 PC4/A4 P9 Vss P10 PC5/A5 P11 PC6/A6 P12 PC7/A7 P13 PB0/A8 P14 PB1/A9 P15 PB2/A10 P16 PB3/A11 P17 Vss P18 PB4/A12 P19 PB5/A13 P20 PB6/A14 P21 PB7/A15 P22 PA0/A16 P23 PA1/A17 P24 Vss P25 PA2/A18 P26 PA3/A19 P27 PA4/A20/IRQ4 P28 PA5/A21/IRQ5 P29 PA6/A22/IRQ6 P30 PA7/A23/IRQ7 P31 EMLE P32 P81/(IRQ1)/TxD3/EDREQ3 P33 P82/(IRQ2)/ETEND2 P34 PH0/CS4/RAS4/WE P35 PH2/CS6/(IRQ6) P37 PH3/CS7/(IRQ7)/OE/CKE P38 WDTOVF P39 NMI P40 VCL P41 P10/PO8/TIOCA0 P42 P11/PO9/TIOCB0 P43 P12/PO10/TIOCC0/TCLKA P44 P13/PO11/TIOCD0/TCLKB P45 P14/PO12/TIOCA1 P46 P15/PO13/TIOCB1/TCLKC P47 P16/PO14/TIOCA2/EDRAK2 P48 P17/PO15/TIOCB2/TCLKD/EDRAK3 P49 Vss P50 P20/PO0/TIOCA3/(IRQ8) P51 P21/PO1/TIOCB3/(IRQ9) P52 P22/PO2/TIOCC3/(IRQ10) P53 P23/PO3/TIOCD3/TxD4/(IRQ11) P54 P24/PO4/TIOCA4/RxD4/(IRQ12) P55 P25/PO5/TIOCB4/(IRQ13) P56 P26/PO6/TIOCA5/(IRQ14) P57 P27/PO7/TIOCB5/(IRQ15) P58 P83/(IRQ3)/RxD3/ETEND3 P59 P84/(IRQ4)/EDACK2 P60 P85/(IRQ5)/SCK3/EDACK3 P61 DCTL P62 PE0/D0 P63 PE1/D1 P64 PE2/D2 P65 PE3/D3 P66 PE4/D4 P67 PE5/D5 P68 PE6/D6 P69 Vss P70 PE7/D7 P71 Vcc P72 PD0/D8 P73 PD1/D9 P74 PD2/D10 P75 PD3/D11 P76 PD4/D12 P77 PD5/D13 P78 PD6/D14 P79 PD7/D15 P80 P60/TMRI0/DREQ0/IRQ8 P81 P61/TMRI1/DREQ1/IRQ9 P82 P62/TMCI0/TEND0/IRQ10 P83 PF0/WAIT P84 PF1/IRQ14/UCAS/DQMU P85 PF2/IRQ15/LCAS/DQML P86 PF3/LWR P87 PF4/HWR P88 PF5/RD P89 PF6/AS P90 PLLVcc P91 RES P92 PLLVss P93 PF7/ ø P94 Vss P95 XTAL P96 EXTAL P97 VCC P98 VCC P99 NC P100 NC P101 Vss P102 STBY P103 P63/TMCI1/TEND1/IRQ11 P104 P64/TMO0/DACK0/IRQ12 P105 P65/TMO1/DACK1/IRQ13 P106 PG0/CS0 P107 PG1/CS1 P108 PG2/CS2/RAS2/RAS P109 PG3/CS3/RAS3/CAS P110 AVcc P111 Vref P112 P40/AN0 P113 P41/AN1 P114 P42/AN2 P115 P43/AN3 P116 P44/AN4 P117 P45/AN5 P118 P46/AN6/DA0 P119 P47/AN7/DA1 P120 P90/AN8 P121 P91/AN9 P122 P92/AN10 P123 P93/AN11 P124 P94/AN12/DA2 P125 P95/AN13/DA3 P126 P96/AN14/DA4 P127 P97/AN15/DA5 P128 AVss P129 PG4/BREQO P130 PG5/BACK P131 PG6/BREQ P132 P50/TxD2/IRQ0 P133 P51/RxD2/IRQ1 P134 P52/SCK2/IRQ2 P135 P53/ADTRG/IRQ3 P136 P35/SCK1/SCL0/(OE)/(CKE) P137 P34/SCK0/SCK4/SDA0 P138 P33/RxD1/SCL1 P139 P32/RxD0/IrRxD/SDA1 P140 P31/TxD1 P141 P30/TxD0/IrTxD P142 MD0 P143 MD1 P144 PH1/CS5/RAS5/SDRAM ø P36 HN1D03FU-TE85R D701 OR 50V 10p CH C709 50V 10p CH C711 CHIP 0 R703 SW0 1/16W CHIP 3.3k R707 POWER_LED TEMP_LED LAMP_LED PSAVE_LED PIC_MUTE FAN_CONT1 FAN_CONT2 FAN_CONT3 P-TX P-RX PW_OSD_EN LAMP_ON LAMP_POWER SCL_400K SDA_400K LAMP_TEMP LED_CONT KEY0 KEY4 SCL_100K_1 P-EXTSW SIRCS SDA_100K_1 INTERLACE RXD_PW TXD_PW POWER_ON LAMP_COVER POWER_PROT FAN_PROT LAMP_PROT CPU & PW ROM TP VPL-CS7 VPL-ES2 R704 10k XX 1/16W CHIP R705 10k XX 1/16W CHIP R724 XX 10k 1/16W CHIP R728 XX 10k 1/16W CHIP TO 3/10 TO 1/10 TO 9/10 TO 10/10 TO 10/10 TO 10/10 TO 2/10,9/10 TO 4/10 TO 8/10 TO 3/10 TO 2/10 TO 9/10 TO 2/10,10/10 TO 5/10 TO 3/10 TO 10/10 TO 1/10 TO 1/10,2/10 TO 2/10 TO 5/10 TO 9/10 TO 2/10 TO 8/10 TO 10/10 TO 10/10 TO 10/10 TO 9/10 TO 5/10 TO 3/10 C (8/10) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com VPL-CS7/ES2 6-10 6-10 2 3 4 5 A B C D E F G H 1 C (9/10) C (9/10) 1 2 2P CN806 TF_OUT TF_IN 1 2 3 WHT 3P CN809 FAN_3 FAN_PROT3 GND 1 2 3 WHT 3P CN812 FAN_1 FAN_PROT1 GND 0uH FB816 0uH FB802 0uH FB805 0uH FB814 0uH FB815 1/16W CHIP 220 R805 0uH FB818 0uH FB804 0uH FB801 5V-1 0uH FB806 0uH FB807 0uH FB808 CPU 0uH FB809 0uH FB810 0uH FB811 0uH FB812 5V-1 5V-2 0uH FB821 1/16W CHIP 100 R836 HN1C01FU-TE85R Q807 FAILSAFE_INVBUFF 1/16W CHIP 10k R817 1/16W CHIP 10k R818 1/16W CHIP 22k R839 1/16W CHIP 22k R840 1/16W CHIP 22k R841 1/16W CHIP 22k R842 DAN202UT106 D807 OR DAN202UT106 D808 OR 10V 0.1 B C824 1/16W CHIP 1k R826 HN1C01FU-TE85R Q806 FAILSAFE_INVBUFF 1/16W CHIP 10k R819 1/16W CHIP 10k R816 1/16W CHIP 33k R827 1/16W CHIP 470 R828 1/16W CHIP 470 R831 1/16W CHIP 33k R830 1/16W CHIP 470 R834 1/16W CHIP 33k R833 1/16W CHIP 10k R814 1/16W CHIP 10k R815 1 2 3 4 5 6 7 8 9 10 11 12 12P CN805 Power_ON Power_ON POWER_LED POWER_LED SUB3.3V SUB3.3V KEY4 KEY4 KEY0 KEY0 GND GND DTA114EUA-T106 Q804 LED_DRIVE DTA114EUA-T106 Q803 LED_DRIVE DTA114EUA-T106 Q802 LED_DRIVE 1/16W CHIP 100 R806 1/16W CHIP 100 R807 1/16W CHIP 100 R808 SEC1801C D801 PSAVE_LED SEC1901C D803 TEMP_LED SEC1901C D802 LAMP_LED 5V-2 2SC4081T106R Q801 LED_SW 1/16W CHIP 10k R802 1/16W CHIP 10k R801 5V-3 6.3V 47 C816 6.3V 47 C803 6.3V 47 C807 6.3V 47 C810 6.3V 47 C804 6.3V 47 C808 1.8V 2.5V 1.55V 1 2 3 4 4P CN802 SUB 3.3V LAMP TEMP LAMP COV GND 0uH FB817 0uH FB803 1/16W CHIP 1k R803 1/16W CHIP 1k R804 2SA1576A-T106-QR Q808 SW 1/16W CHIP 10k R837 0uH FB820 1 2 3 4 5 5P CN807 FLAG OE ACOM LAMP_ON HI/LOW 0uH FB819 0uH FB822 3.3V-3 17V 3.3V-2 3.3V-2 3.3V-1 3.3V-1 3.3V-1 3.3V-1 3.3V-1 25V 47 C820 25V 47 C821 25V 47 C822 10V 0.1 B C806 10V 0.1 B C802 10V 0.1 B C809 10V 0.1 B C805 10V 0.1 B C801 10V 0.1 B C817 10V 0.1 B C818 10V 0.1 B C819 10V 0.1 B C823 0uH FB813 JL801 TP801 XX 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 24P CN804 PCONT FAN_CONT1 PPROT GND GND FAN+B FAN+B GND GND SUB+6V GND GND 6V 6V GND GND D3.3V D3.3V GND GND 17V 17V GND GMD 25V 47 C826 0uH FB823 1005 10V 0.1 B C827 1/16W CHIP 22k R846 1/16W CHIP 330 R847 1/16W CHIP 330 R848 5 4 3 2 1 TK11125CSCL-G IC802 2.5V_REG 1/16W RN-CP 10k R820 1005 10V 0.1 B C828 1005 16V 0.01 B C829 I O ADJ AIC1117A-18PYJTR IC804 1.8V_REG I O ADJ AIC1117A-33PYJTR IC805 3.3V_REG 1005 10V 0.1 B C830 1/16W CHIP 470 R849 1/16W CHIP 220 R850 1/16W CHIP 220 R851 I O ADJ AIC1084-PEJTR IC806 1.55V_REG I O ADJ AIC1117A-50PYJTR IC801 5V_REG I O ADJ AIC1117A-50PYJTR IC803 5V_REG 1 2 3 RED 3P CN810 FAN_2 FAN_PROT2 GND 1 2 3 BLU 3P CN811 FAN_2 FAN_PROT2 GND JL802 JL803 JL804 JL805 JL806 JL807 JL808 JL809 JL810 JL812 JL813 JL814 1 2 3 4 5 6 6P CN803 SUB 5V SIRCS GND LED_VCC LED_CONT NC 1 2 3 4 5 BA00ASFP-E2 IC808 FAN REG CTL Vcc GND OUT C 1 2 3 4 5 BA00ASFP-E2 IC809 FAN REG CTL Vcc GND OUT C 1/16W CHIP 2.2k R853 1/16W CHIP 2.2k R852 1/16W CHIP 2.2k R854 1 2 3 4 5 BA00ASFP-E2 IC807 CTL Vcc GND OUT C 0uH FB824 0uH FB825 D1FS4A-TA D810 DROP 1/16W CHIP 47k R843 1608 25V 0.1 F C837 D1FS4A-TA D811 DROP 1/16W CHIP 4.7k R835 1/16W CHIP 4.7k R832 1/16W CHIP 4.7k R829 RD5.6SB-T1 D812 RD5.6SB-T1 D813 RD5.6SB-T1 D814 RD5.6SB-T1 D815 RD5.6SB-T1 D805 1 2 3 4 4P CN815 FAN_2 FAN_PROT2 GND FAN+B_SA D1FS4A-TA D804 D1FS4A-TA D806 1608 25V 0.1 F C862 10V 0.1 B C859 JL820 1/16W CHIP 100k R868 0uH FB826 16V 220p CH C861 1 2 2P CN814 SP+ SP- MA3J14700LSO D818 DTC114EUA-T106 Q809 INV-SW MA3J14700LSO D819 0uH FB827 1/16W RN-CP 120k R871 1608 25V 0.1 F C858 3216 10V 10 F C857 XX R870 5V-2 JL821 3216 10V 10 F C856 1uH L801 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 TPA2001D1PWR IC815 AUDIO_AMP INP INN ST DWN GAIN0 GAIN1 PVDD OUTP GNDP GNDN OUTN PVDD VDD ROSC COSC AGND BYPASS 3216 16V 0.47 F C860 1/16W CHIP 10k R869 10V 0.1 B C849 10V 0.1 B C855 JL817 3216 10V 10 F C842 JL816 9V I2C_100K 10V 0.1 B C853 20 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 TDA7309D013TR IC814 AUDIO_PROCESSOR REC_OUT_L OUTL CSM SDA SCL DGND GND GND OUTR REC_OUT_R IN3R LOUDR IN2R IN1R CREF VS IN1L IN2L LOUDL IN3L 10V 0.1 B C854 1/16W CHIP 47k R864 1/16W CHIP 470k R857 J801 JL819 1/16W CHIP 100 R860 1/16W CHIP 100 R859 RD9.1SB2-T1 D817 PROTECT JL815 10V 0.1 B C850 1/16W CHIP 470k R856 25V 47 C846 XX C851 3216 10V 10 F C843 AU_MUTE 1/16W CHIP 100 R866 XX C848 RD9.1SB2-T1 D816 PROTECT 1/16W CHIP 47k R865 1/16W CHIP 100 R867 25V 0.1 F C840 9V VCC GND OUT BA09FP-E2 IC811 9V REG 17V 25V 47 C845 POS_DET 1608 25V 0.1 F C852 1/16W CHIP 100k R863 5 4 3 2 1 LMC7101BIM5X IC810 BUFFER OUT VCC V+ + - V- GND 10V 0.1 B C839 1608 25V 0.1 F C841 1/16W CHIP 10k R858 1608 25V 0.1 F C847 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 BA6288FS-E2 IC812 MOTOR DRIVE GND NC OUT1 VM VCC FIN NC NC NC NC RIN VREF NC OUT2 NC RNF 3.3V-2 1 2 3 4 5 5P CN813 M+ M- T1 T2 T3 10V 0.1 B C844 JL818 TH801 TILT_EN 1/16W CHIP 10k R855 8 7 6 5 4 3 2 1 TC7WH125FK(TE85R) IC813 3STATE_BUFF G1 A1 Y2 GND A2 Y1 G2 VCC 3.3V-2 1/16W CHIP 10k R861 TILT+ 10V 0.1 B C838 1/16W CHIP 10k R862 TILT- FAN_PROT FAN_CONT2 FAN_CONT1 LAMP_TEMP LAMP_ON LAMP_PROT LAMP_POWER LAMP_LED SIRCS LED_CONT FAN_CONT3 PSAVE_LED TEMP_LED LAMP_COVER KEY0 KEY4 POWER_LED POWER_ON SDA_100K_1 SCL_100K_1 H V L/NR G FAN-C FAN-D FAN-B FAN-A AUDIO SP FOOT TO 8/10 TO 8/10 TO 8/10 TO 2/10,8/10 TO 8/10 C (9/10) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com VPL-CS7/ES2 2 3 4 5 1 6-11 6-11 A B C D E F G H C (10/10) C (10/10) 1/16W CHIP 22 R993 1/16W CHIP 22 R994 TILT_X TILT_Y 3.3V-2 10V 0.1 B C935 *R936 5V-3 CHIP 0 R906 1/16W CHIP 100 R921 1/16W CHIP 47k R930 1/16W CHIP 1k R916 15P CN901 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 MA3J14700LSO D907 PROTECT *R938 J901 MA3J14700LSO D906 PROTECT 1/16W CHIP 47k R929 1005 16V 0.01 B C903 H_SYNC 1005 16V 0.01 B C902 SOG 3216 10V 22 F C905 HN1D03FU-TE85R D908 PROTECT 1/16W CHIP 1k R911 V_SYNC MA3J14700LSO D905 PROTECT *R937 2012 10V 4.7 F C904 CHIP 0 R907 1/16W CHIP 47k R931 1/16W CHIP 100 R922 1005 16V 0.01 B C901 V_IN CHIP R939 XX CHIP XX R940 CHIP 47 R935 1/16W 5V-1 6.3V 47 C947 6.3V 47 C948 6.3V 47 C949 1/16W CHIP 47k R901 1/16W CHIP 47k R902 1/16W CHIP 47k R903 DDC_SW0 DAN202UT106 D909 OR SDA_100K_2 1/16W CHIP 10k R941 8 7 6 5 4 3 2 1 24LC21AT/SN IC901 DDC_EEPROM NC1 NC2 NC3 GND SDA SCL VCLK VCC JL901 10V 0.1 B C906 1/16W CHIP 220 R924 SCL_100K_2 1/16W CHIP 47 R912 1/16W CHIP 10k R995 DDC_WE 1/16W CHIP 47 R920 DTC114EUA-T106 Q903 INV_SW DTC114EUA-T106 Q901 INV_SW 1/16W CHIP 10k R932 1/16W CHIP 10k R928 JL904 JL905 JL906 JL907 JL908 JL909 JL910 JL911 JL912 JL913 JL914 JL915 *C914 5V-3 MA3J14700LSO D914 PROTECT 9V *R968 25V 47 C911 MA3J14700LSO D916 PROTECT 1 2 3 4 5 6 7 8 9 9P CN904 I/O_R GND I/O_G GND I/O_B GND OUT_H OUT_V GND 8 7 6 5 4 3 2 1 SN75453BPSR *IC904 SYNC_DRV 1A 1B 1Y GND 2Y 2A 2B VCC *R964 *R967 *R976 *R975 *C953 MA3J14700LSO D915 PROTECT *R978 1/16W CHIP 1k R971 SW0 1/16W CHIP 100k R998 DTC114EUA-T106 Q904 INV_SW HN1D03FU-TE85R *D917 PROTECT RD3.9SB-T1 D902 PROTECT RD3.9SB-T1 D918 PROTECT RD3.9SB-T1 D919 PROTECT RD3.9SB-T1 D920 PROTECT RD3.9SB-T1 D921 PROTECT 1 2 3 4 5 5P CN903 3.3V-2 TILT_X TILT_Y GND TA 0uH FB901 RN-CP 15 FB902 1/10W RN-CP 15 FB903 1/10W 1/16W CHIP 100 R923 TA CHIP 0 R933 CHIP 0 R934 *R943 *R942 *R944 3.3V-3 3.3V-3 *R951 *R950 *R952 1uH L905 *L904 *C956 RD5.6SB-T1 D903 RD5.6SB-T1 D904 RD5.6SB-T1 D912 RD5.6SB-T1 D913 3 4 1 2 G1 G2 6P CN902 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 TC74HC4052AFT(EL) IC902 DDC SW 0Y 2Y Y_Out 3Y 1Y INH VEE GND B A 3X 0X X_Out 1X 2X VCC 10V 0.1 B C957 CHIP 0 R925 CHIP 0 R926 CHIP 0 R927 RN-CP 15 FB904 1/10W *R972 *R973 *R974 *R977 SOG_B 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 EL5364IUZ-T7 *IC919 INA+ CEA VS- CEB INB+ NO CEC INC+ INC- OUTC NO INB- OUTB VS+ OUTA INA- 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 EL5364IUZ-T7 IC920 INA+ CEA VS- CEB INB+ NC CEC INC+ INC- OUTC NC INB- OUTB VS+ OUTA INA- *R997 *R996 *R991 *R001 *R002 *R003 DTC114EUA-T106 *Q905 INV_SW *R004 25V 0.1 F C907 *R980 *R982 *R981 *R983 *R961 *R962 *R984 *R985 *R992 *R999 *R989 *R990 *R946 *R947 *R945 1/10W RN-CP 150 R965 1/10W RN-CP 150 R966 1/10W RN-CP 150 R970 1/10W RN-CP 150 R963 1/10W RN-CP 150 R969 1/10W RN-CP 150 R979 1/16W CHIP 680 R904 1/16W CHIP 680 R959 1/16W CHIP 680 R954 1/16W CHIP 680 R905 1/16W CHIP 680 R949 1/16W CHIP 680 R948 CHIP 47 R987 1/16W CHIP 47 R986 1/16W CHIP 47 R988 1/16W MON_OUT_EN *R005 *R006 *R958 *R960 *R956 *R953 *R957 *R955 1/10W RN-CP 150 R909 1/10W RN-CP 150 R919 1/10W RN-CP 150 R913 1/10W RN-CP 150 R914 1/10W RN-CP 150 R910 1/10W RN-CP 150 R918 1/10W RN-CP 150 R915 1/10W RN-CP 150 R908 1/10W RN-CP 150 R917 1uH L902 SC SY CVBS VSYNC HSYNC R G B S_IN VIDEO_IN INPUT_A SA TO 1/10 TO 2/10 TO 2/10 TO 2/10,8/10 TO 8/10 TO 8/10 TO 8/10 TO 2/10 TO 2/10 TO 8/10 VPL-CS7 VPL-ES2 C914 0.1 0.1 25V 25V F F C953 XX 0.1 6.3V B C956 XX 0.1 6.3V B D917 HN1D03FU-TE85R XX IC904 SN75453BPSR XX IC919 XX RL5364IUZ-T7 L904 XX 1uH Q905 XX DTC114EUA-T106 R001 XX 0 CHIP R002 XX 0 CHIP R003 XX 0 CHIP R004 XX 10k 1/16W CHIP R005 XX 0 CHIP R006 0 XX CHIP R936 47 XX 1/16W CHIP R937 47 XX 1/16W CHIP R938 47 XX 1/16W CHIP R942 0 XX CHIP R943 0 XX CHIP R944 0 XX CHIP R945 XX 47 1/16W CHIP R946 XX 47 1/16W CHIP R947 XX 47 1/16W CHIP R950 XX 47 1/16W CHIP R951 XX 47 1/16W CHIP R952 XX 47 1/16W CHIP R953 XX 680 1/16W CHIP R955 XX 680 1/16W CHIP R956 XX 680 1/16W CHIP R957 XX 680 1/16W CHIP R958 XX 680 1/16W CHIP R960 XX 680 1/16W CHIP R961 XX 150 1/16W CHIP R962 XX 150 1/16W CHIP R964 330 XX 1/10W CHIP R967 330 XX 1/10W CHIP R968 330 XX 1/10W CHIP R972 XX 47 1/16W CHIP R973 XX 47 1/16W CHIP R974 XX 47 1/16W CHIP R975 47 XX 1/16W CHIP R976 47 XX 1/16W CHIP R977 XX 0 CHIP R978 330 XX 1/10W CHIP R980 XX 150 1/10W CHIP R981 XX 150 1/10W CHIP R982 XX 150 1/10W CHIP R983 XX 150 1/10W CHIP R984 XX 150 1/10W CHIP R985 XX 150 1/10W CHIP R989 XX 150 1/10W CHIP R990 XX 150 1/10W CHIP R991 XX 0 CHIP R992 XX 150 1/10W CHIP R996 XX 0 CHIP R997 XX 0 CHIP R999 XX 150 1/10W CHIP C (10/10) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com VPL-CS7/ES2 6-12 6-12 C C 1 20 2 19 3 18 4 17 5 16 6 15 7 14 8 13 9 12 10 11 CLAMP GEN EDGE SW LOGIC LOGIC SYNC SEP V. SYNC SEP V TIME GATE V DET V SHAPE H DET H SHAPE V S/S IN V S/S OUT VD+ OUT HD+ OUT CLAMP+ OUT CLAMP+ TIMING CLAMP SW VCC HD– OUT V. POL V. STATE H. STATE H. POL GND GREEN IN V IN V DET V TIME GATE SW COMP/H IN COMP/H DET C (2/10) M52347FP-TE (IC202) C (2/10) SN74LV00APWR (IC204) 14 13 12 11 10 9 8 1 2 3 4 5 6 7 GND VCC C (2/10) SN74LV244APWR (IC205) 1 2 3 4 5 6 7 14 13 12 11 10 9 8 1OE 1A 1Y 2OE 2A 2Y 3OE 3A 3Y 4OE 4A 4Y GND VCC C (3/10) TC74LCX125FT(EL)(IC302) 20 19 18 17 16 15 14 13 12 11 1 2 3 4 5 6 7 8 9 10 1G 1A1 2Y4 1A2 2Y3 1A3 2Y2 1A4 2Y1 GND 2A4 1Y4 2A3 1Y3 2A3 1Y2 2A4 1Y1 2G Vcc C (1/10, 3/10, 4/10, 8/10) S80928CNMC-G8Y-T2 (IC103, IC303, IC403, IC404, IC704) VDD 2 VSS CD 4 5 OUT 1 VREF DELAY 27 26 25 17 20 18 29 40 48 28 24 12 6 23 33 34 35 36 37 38 39 6dB PEAK HOLD LEVEL DET. POLARITY DISTINCT. V SYNC SEP. SYNC SEP. I2C bus DEC. YPbPr YCbCr (CCIR) MATRIX SELECTOR YPbPr YCbCr (BTA) RGB YCbCr 41 42 43 44 45 46 47 1 2 3 4 5 7 8 9 10 11 15 16 13 14 IN1 to IN4 SELECTOR INPUT_SEL (2) SELSTB_1 (1) SELSTB_2 (1) + DECL1_1 (2) + DECL2_1 (2) + DECL3_1 (2) + DECSW_1 (1) + DECL1_2 (2) + DECL2_2 (2) + DECL3_2 (2) DECSW_2 (1) + EH (1) + EV (1) HD_TC (1) HSEP_SEL (1) V_TC (2) MAT_OUT (2) +3-STATE (1) YGAIN (4) CBGAIN (4) CRGAIN (4) CLK_SEL (1) GAIN_SEL (2) Y Y/Cb/Cr Cb/Cr 1 0 H V H SYNC WIDTH MACRO VISION 22 DUMMY SYNC CLOCK GEN. CLAMP CLAMP CLP & 3SYNCP 3STATE SYNC DET. HYSW (1) SYNC COUNTER PRIORITY RANK HV > CS > Y/G 6dB AMP. H V H V H V 0 1 0 1 2, 3 0 1 2 3 H_WIDTH (2) MACRO (1) HS_MASK (1) FIX_SYNC (2) SELDUM (1) + H_NUMBER_H (2) + H_NUMBER_L (8) + V_NUMBER_H (2) + V_NUMBER_L (8) 30 31 32 SELY_OUT SELCB_OUT SELCR_OUT CLP_SW EXTCLK/XTAL SELV_OUT SELH_OUT IREF Vcc1 GND1 Vcc2 GND2 Vcc3 GND3 H_PH YG_IN YG_OUT V_PH SCL SDA ADDRESS IN1_1 IN1_2 IN1_3 IN1_H/L1 IN1_V/L2 IN1_L3 IN1_SW IN2_1 IN2_2 IN2_3 IN2_H/L1 IN2_V/L2 IN2_L3 IN2_SW IN3_1 IN3_2 IN3_3 IN3_H IN3_V IN4_1 IN4_2 IN4_3 IN4_H IN4_V CLP_CR C (2/10) CXA2171AQ-T6 (IC203) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com VPL-CS7/ES2 6-13 6-13 C C C (4/10) SN74AHCT541PWR (IC407, IC408, IC409) 1 G1 VDD 10 9 8 7 6 5 4 3 2 G2 Y1 Y2 Y3 Y4 Y5 Y6 Y7 Y8 20 11 12 13 14 15 16 17 18 19 GND A8 A7 A6 A5 A4 A3 A2 A1 C (4/10) TC7WH125FK (TR85R) (IC402) G1 A1 Y2 GND VDD G2 Y1 A2 1 2 3 4 8 7 6 5 C (5/10, 6/10, 7/10) CXA7005R-T4 (IC501, IC601, IC651) C (4/10) TC74VHCT540AFT(EL) (IC410) 8 15 16 10 14 13 12 11 9 6 7 4 2 3 1 VCC GND 20 19 18 17 5 C (3/10) CY25023SZC-1T (IC304) C (3/10) MX29LV800ATTC-70G-751PW103 (IC306) OUTPUT DIVIDERS AND MUX PROGRAMMABLE CONFIGURATION 5 SSCLK 1 XIN/CLKIN 8 XOUT 3 OE 7 SSON 4 VSS 2 VDD 6 NC OSC. C XIN PLL WITH MODULATION CONTROL C XOUT WRITE STATE MACHINE (WSM) PROGRAM/ERASE HIGH VOLTAGE CONTROL INPUT LOGIC ADRESS LATCH AND BUFFER Y-PASS GATE FLASH ARRAY STATE REGISTER COMMAND DATA DECODER COMMAND DATA LATCH SENSE AMPLIFIER PROGRAM DATA LATCH PGM DATA HV I/O BUFFER X-DECODER Y-DECODER ARRAY SOURCE HV CE OE WE A0-A18 Q0-Q15/A1 1 8· 17 24· 25· 48 29 36· 38 45 26 28 11 DGND D_IN0 D_IN1 D_IN2 D_IN3 D_IN6 D_IN7 D_IN8 D_IN9 DGND D_IN5 D_IN4 CLK FRP PRG DIRC DGND VDD AGND AGND AGND STATUS VCC FRINV PVCC VCOM_OUT SIG_OUT6 SIG_OUT5 SIG_OUT4 SIG_OUT3 SIG_OUT2 SIG_OUT1 SID_OUT PVCC PGND PGND ADDR0 ADDR1 REF_IN REF_OUT AGND AGND VCC SENB SCLK SDAT SIF TG SID DC_GEN D/A D/A D/A D/A D/A D/A Driver REF D/A Driver Driver Driver Driver Driver Digital DGND DGND 36 35 34 33 32 31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 48 47 46 45 44 43 42 41 40 39 38 37 Vcc CTL OUT C GND 2 1 3 + – Reference Voltage 4 5 C (5/10, 9/10) BA00ASFP-E2 (IC502, IC807, IC808, IC809) C (9/10) TK11125CSCL-G (IC802) OVER HEAT & OVER CURRENT PROTECTION BANDGAP REFERENCE CONTROL CIRCUIT VIN VOUT VCONT NP GND 1 2 3 5 4 500kΩ 320kΩ 1 3 IN EXCLUSIVE IC(STABILIZER, OVER CURRENT & HEAT PROTECTION, ON/OFF CONTROL) OUT 5 GND 2 ON/OFF 4 ADJ C (5/10) PQ20WZ1UJ00H (IC503) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com VPL-CS7/ES2 6-14 6-14 1 2 3 4 8 7 6 5 1 A 1 B 1 Y GND VCC 2 B 2 A 2 Y C (10/10) SN75453BPSR (IC904) 1 5 2 4 3 6 7 8 SELECT A SELECT B 3 2 1 0 3 2 1 0 INH Y1 Y3 Y Y1 Y0 VEE VSS X3 X0 X X1 X2 VDD A B 9 12 14 15 11 16 13 10 C (10/10) TC74HC4052AFT(EL) (IC902) C (9/10) TPA2001D1PWR (IC815) 1 19 18 17 16 15 11 12 13 14 20 LOUDL IN2L IN1L VS CREF IN3R LOUDR IN2R IN1R IN3L 2 3 4 5 6 7 8 9 10 RECOUTL OUTL CSM SDA SCL DGND GND ADD OUTR RECOUTR MUTE VOLUME + LOUDNESS SERIAL BUS DECODER + LATCH MUTE VOLUME + LOUDNESS SOFT MUTE SUPPLY GAIN ADJUST GAIN ADJUST 1 16 2 14 13 DEGLITCH DEGLITCH RAMP GEN GATE DRIVE COSC 15 AGND 12 VDD 11 PVDD 10 OUTN 9 PGND BYPASS ROSC GATE DRIVE OC DET START-UP PROTECTION BIAS AND REF VDD OK THERMAL GAIN 6 PVDD 7 OUTP 8 PGND 5 GAIN1 4 GAIN0 3 SHUTDOWN INN INP SD 2 C (9/10) TDA7309D013TR (IC814) C C G1 A1 Y2 GND VDD G2 Y1 A2 1 2 3 4 8 7 6 5 C (9/10) TC7WH125FK(TE85R) (IC813) C (10/10) 24LC21AT/SN (IC901) 5 7 6 8 4 1 2 3 I/O CONTROL LOGIC MEMORY CONTROL LOGIC XDEC EEPROM ARRAY PAGE LATCHES H/V GENERATOR SENSE AMP R/W CONTROL YDEC SDA VCLK SCL VCC VSS NC NC NC C (10/10) EL5364IUZ-T7 (IC919, IC920) 1 2 3 16 15 14 13 INA+ CEA VS- CEB 5 12 INB+ 11 NC 10 CEC 8 9 INC+ INA- OUTA VS+ OUTB INB- NC OUTC INC- 4 6 7 1 GND 2 NC 3 OUT1 4 VM DRIVER 5 VCC 6 FIN 7 NC 8 NC RNF NC OUT2 NC VREF CONTROL LOGIC RIN NC NC TSD POWER SAVE 16 15 14 13 12 11 10 9 C (9/10) BA6288FS-E2 (IC812) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com VPL-CS7/ES2 2 3 4 5 1 6-15 6-15 A B C D E F G H G (1/2) G (1/2) JL101 JL102 VDR101 SURGE ABSORBER 250V 0.22 C101 250V 0.47 C104 TH101 ~ ~ D10XB80 D101 BRIDGE RECTIFIER 450V 0.47 C105 450V 2.2 C106 RM11A D102 RECTIFIER 1/4W FPRD 10 R102 S 2SK2195F04 Q101 PFC SWITCH FSF10A60 D103 RECTIFIER D1FS4-TB D104 RECTIFIER 1/10W RN-CP 150k R105 450V 220 C107 1/10W RN-CP 330k R106 1/10W RN-CP 330k R107 1/10W RN-CP 330k R108 1/10W CHIP 470 R110 1/10W RN-CP 10k R111 1/10W RN-CP 10k R112 25V 0.01 B C108 16V 0.22 B C110 1/10W RN-CP 330k R113 1/10W RN-CP 330k R114 1/10W RN-CP 330k R115 1/10W RN-CP 330k R116 1/10W CHIP 22k R117 1/10W RN-CP 10k R118 35V 47 C111 50V 0.1 B C112 2SA1213Y-TE12L Q102 PFC ON/OFF SWITCH 1/10W CHIP 4.7k R119 1/10W CHIP 10k R120 8 7 6 5 4 3 2 1 MC34262DR2 IC102 PFC CONTROL F/B COMP MULTI ISENSE ZERO GND DRIVE VCC VCC POWER_ON DC+ 1 3 3P CN102 BLK DC+ DC- 1 3 3P CN101 WHT AC(N) AC(L) 250V 4700p E C102 250V 4700p E C103 FH101 FH102 1/2W 680k R101 50V 1000p B C109 1 2 3 4 6.7mH L101 F101 5A 250V 5 2 550uH L102 5W RB 0.08 R104 1 10 2 5 6 4 9 3 7 200uH L103 DC+ DC- CHIP 0 R301 Mount Mecha 409912401 A101 HEAR SINK TO 2/2 TO 2/2 ! ! ! ! ! ! ! ! ! ! ! ! ! ! ! ! ! G (1/2) MC33262DR2 (IC102) Zero Current Detect input 5 Multiplier 3 GND 6 Compensation 2 VCC 8 Drive Output 7 Current Sense Input 4 Voltage Feadback Input 1 Undervoltage Lockout Multiplier Quickstart Error A mp Overvoltage Comparator Vref 1.08 Vref Zero Current Delector 2.5V Reference Multiplier, Latch PWM, Timer, & Logic w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com VPL-CS7/ES2 6-16 6-16 2 3 4 5 A B C D E F G H 1 G (2/2) G (2/2) 1/10W RN-CP 15k R201 1/10W RN-CP 3.3k R202 1/4W FPRD 1k R206 1/10W RN-CP 3.3k R207 1/10W CHIP 680 R209 1/10W CHIP 100 R211 1/4W FPRD 4.7 R212 1/2W RF 0.1 R213 1/10W CHIP 10 R214 1/10W CHIP 10k R215 1/10W CHIP 10 R216 1/10W CHIP 10k R217 RD18M-T1B1 D201 PROTECTOR 25V 0.01 B C201 50V 1000p B C202 10V 2.2 B C204 25V 0.01 B C206 MA111-TX D202 SURGE ABSORBER 25V 0.01 B C208 UF4005PKG23 D203 BOOST RECTIFIER 1/10W CHIP 330 R218 PC123GY2 PH201 PCONT COUPLER PC123GY2 PH202 FEEDBACK COUPLER JL201 JL202 JL203 D1FS4A-TA D204 RECTIFIER 50V 220 C211 POWER_ON VCC DC- DC+ 1/10W CHIP 47k R220 1/10W CHIP 10k R221 1/10W CHIP 1k R222 1/10W CHIP 10k R224 10 4.7 B C212 2SA1162-YG-TE85L Q203 LATCH 2SC2712-YG-TE85L Q204 LATCH XX C213 D10SC6M D206 RECTIFIER 25V 820 C214 4.7uH L201 MA111-TX D207 RECTIFIER 1/10W CHIP 100k R225 1/10W CHIP 47k R226 D10SC4M D209 RECTIFIER 10V 2200 C216 4.7uH L202 MA111-TX D210 RECTIFIER 1/10W CHIP 3.3k R227 1/10W CHIP 47k R228 1/10W CHIP 1k R229 8 7 6 5 4 3 2 1 S1 S2 S3 G D1 D2 D3 D4 SI4425DY-T1 Q205 17V ON/OFF SWITCH 8 7 6 5 4 3 2 1 S1 S2 S3 G D1 D2 D3 D4 SI4425DY-T1 Q206 6V ON/OFF SWITCH 1/10W CHIP 3.3k R230 1/10W CHIP 470 R231 3 1 2 TL431CPK-E2 IC202 SHUNT REGULATOR 16V 0.1 B C218 1/10W RN-CP 12k R233 1/10W CHIP 2.2k R235 1/10W RN-CP 10k R236 16V 0.1 B C219 DTC144EUA-T106 Q207 PCONT SWITCH 16V 0.1 B C220 MA111-TX D212 RECTIFIER 1/10W CHIP 2.2k R239 1/10W CHIP 10k R241 1/10W CHIP 10k R242 1W RS 0.33 R219 10uH L204 4.7uH L205 16V 0.1 B C237 DTC144EUA-T106 Q210 17V DOWN DETECTOR DTC144EUA-T106 Q211 6V DOWN DETECTOR DTC144EUA-T106 Q212 D3.3V DOWN DETECTOR DTC144EUA-T106 Q213 INVERTOR DTC144EUA-T106 Q214 POWER PROTECTOR 1/10W CHIP 10k R257 1/10W CHIP 15k R258 1/10W CHIP 4.7k R259 1/10W CHIP 10k R260 1/10W CHIP 4.7k R261 1/10W CHIP 15k R262 1/10W CHIP 10k R263 MA111-TX D215 RECTIFIER MA111-TX D216 RECTIFIER MA111-TX D217 RECTIFIER 1/10W CHIP 10k R264 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 24P CN201 GND GND 17V 17V GND GND D3.3V D3.3V GND GND 6V 6V GND GND SUB5V GND GND FAN+B FAN+B GND GND PPROT FAN CONT1 PCONT D3.3V 6V 17V JL204 8 7 6 5 4 3 2 1 UPC393G2-E2 IC203 DELAY OUT1 -IN1 +IN1 GND +IN2 -IN2 OUT2 VCC 4.7uH L207 10V 120 C230 1 2 3 4 5 6 LTC1772CS6 IC205 D3.3V D/D CONVERTOR CONT ITH/RUN GND VFB SENSE VIN PGATE 1/10W CHIP 10k R250 1608 50V 220p CH C229 8 7 6 5 4 3 2 1 S1 S2 S3 G D1 D2 D3 D4 SI4403DY-T1 Q209 D/D CONVERTOR SWITCH EC31QS03L-TE12L D214 FLYWHEEL 6.3V 220 C234 1608 16V 0.1 B C235 1/10W RN-CP 180k R251 1/10W RN-CP 33k R252 1/10W RN-CP 68k R254 1W CHIP 0.047 R253 1/10W CHIP 22k R240 SUB5 6V 17V D3.3V JL205 JL206 JL207 JL208 JL209 JL211 JL212 1/10W RN-CP 15k R208 S 2SK2876-01MR-F122 Q201 2SK2876-01 MAIN CONVERTER SWITCH S 2SK2876-01MR-F122 Q202 2SK2876-01 MAIN CONVERTER SWITCH 1/10W CHIP 47k R223 1/10W CHIP 10k R210 1/10W CHIP 2.2k R265 16V 10 C203 35V 47 C205 35V 47 C207 DTC144EUA-T106 Q215 FAN+B DOWN DETECTOR 1/10W CHIP 10k R266 MA111-TX D218 RECTIFIER 1/10W CHIP 15k R267 1/10W CHIP 4.7k R268 FAN+B FAN+B RD30SB-T1 D219 PROTECTOR RD39SB-T1 D205 DETECTOR 1/10W RN-CP 330k R203 1/10W RN-CP 330k R204 1/10W RN-CP 330k R205 25V 10 C215 B 3225 25V 10 C217 B 3225 25V 10 C221 B 3225 6.3V 100 C236 1/10W CHIP 10k R238 1/10W CHIP 47k R237 16V 22 C238 1/10W CHIP 10 R269 1608 16V 0.1 B C240 1608 50V 100p CH C241 1/10W CHIP 1k R232 1/10W RN-CP 4.7k R234 1 2 3 4 5 BA00AST-V5 IC204 FAN REGURATOR CTL VCC GND OUT C 2012 50V 0.1 B C222 35V 22 C223 1/10W CHIP 47k R243 1/10W CHIP 47k R244 1/10W RN-CP 15k R245 1/10W RN-CP 22k R246 1/10W RN-CP 3.3k R247 3225 25V 10 B C224 JL210 800V PP 4700p C210 50V 0.1 C209 B I O ADJ AIC1117A-50PYJTR IC206 5V REGURATOR 1/10W CHIP 220 R255 1/10W CHIP 220 R256 25V 47 C242 24 21 22 23 1 2 3 4 5 6 7 8 9 10 19 20 14 13 12 11 18 17 15 16 MCZ3001UB IC201 MAIN CONVERTER CONT Vsense F/B Ct NC Rt GND GND GND GND GND GND Timer NC SS Vc1 OCP Vc2 PGND NC VGL VB VS VGH VD 1 2 4 5 6 7 8 9 10 T202 DC+ D3.3V 6V 17V SUB5 FAN+B DC- SUB5 ! TO 2/2 G (2/2) BA00AST-V5 (IC204) Vcc CTL OUT C GND 2 1 3 + – Reference Voltage 4 5 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com VPL-CS7/ES2 2 3 4 5 1 6-17 6-17 A B C D E F G H H H S10 S12 S11 S13 1/16W CHIP 150 R10 1/16W CHIP 180 R12 1/16W CHIP 150 R11 1/16W CHIP 180 R14 1/16W CHIP 100 R18 1/16W CHIP 100 R20 1/16W CHIP 100 R22 1/16W CHIP 100 R23 G R SEC2422C D10 POWER_LED G R SEC2422C D11 POWER_LED HN1D03FU-TE85R D12 PROTECT HN1D03FU-TE85R D13 PROTECT 1 2 3 4 5 6 7 8 9 10 11 12 12P CN10 Power_ON Power_ON POWER-LED POWER-LED SUB+3.3V SUB+3.3V KEY4 KEY4 KEY0 KEY0 GND GND JL10 10V 0.1 B C10 DTA114EUA-T106 Q10 SW DTA114EUA-T106 Q11 SW S15 1/16W CHIP 2.7k R13 1/16W CHIP 1.2k R15 1/16W CHIP 680 R16 1/16W CHIP 390 R17 1/16W CHIP 270 R19 1/16W CHIP 220 R21 HN1C01FU-TE85R Q12 SW 1/16W CHIP 4.7k R24 1/16W CHIP 47k R25 1/16W CHIP 47k R26 1/16W CHIP 47k R27 XX R28 S14 2 4 6 3 1 5 RIGHT UP LEFT DOWN MENU ON/STBY ON/STBY b e c a g d INPUT POWER H w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com VPL-CS7/ES2 6-18 6-18 2 3 4 5 A B C D E F G H 1 NR, QA (VPL-ES2), Q (VPL-CS7) NR, QA (VPL-ES2), Q (VPL-CS7) 1/16W CHIP 47 R80 10V 10 F C80 1 2 3 3P CN80 SUB 5V SIRCS GND VCC OUT GND KRM-TR303E-TP IC001 1/16W CHIP 100 R81 NR 1 2 3 4 5 6 7 8 9 9P CN601 I/O_R GND I/O_G GND I/O_B GND OUT_H OUT_V GND 1/10W CHIP 150 R605 1/10W CHIP 150 R606 1/10W CHIP 150 R603 1/10W CHIP 150 R604 1/10W CHIP 150 R601 1/10W CHIP 150 R602 25V 0.01 B C602 25V 0.01 B C604 25V 0.01 B C606 6.3V 47 C601 6.3V 47 C603 6.3V 47 C605 R J601 QA VPL-ES2 CHIP 0 R5 16V 330 C1 CHIP 0 R7 CHIP 0 R3 16V 330 C3 CHIP 0 R2 1/10W CHIP 47 R1 16V 330 C2 1/10W CHIP 47 R4 1/10W CHIP 47k R11 CHIP 0 R008 CHIP 0 R6 15P CN2 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 1/10W CHIP 47k R9 1/10W CHIP 47k R10 1 2 3 4 5 6 7 8 9 9P CN1 OUT_R GND OUT_G GND OUT_B GND OUT_H OUT_V GND Q VPL-CS7 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com VPL-CS7/ES2 2 3 4 5 1 6-19 6-19 A B C D E F G H SA, S, V SA, S, V CHIP R701 10 1/10W JL706 1 2 3 4 5 5P CN701 3.3V-2 TILT_X TILT_Y GND TA TH701 25V B C701 0.01 JL701 JL702 JL703 JL704 JL705 JL707 1 2 3 4 5 6 7 8 MXS3125GL IC701 ACCELEROMETER 1 2 3 4 4P CN702 FAN_2 FAN_PROT2 GND FAN+B_SA 1 2 3 WHT 3P CN703 FAN_2 FAN_PROT2 GND *R709 *R710 8 7 6 5 4 3 2 1 S1 S2 S3 G D1 D2 D3 D4 SI4425DY-T1 *Q701 SW D1FS4A-TA *D701 RECTIFIER 16V 0.1 B C704 16V 0.1 B C702 *R708 *R707 *R705 *R704 *R706 *C705 3216 10V 10 F C703 1 2 3 4 5 PQ20WZ1U *IC703 FAN REGURATOR VIN CONT VOUT ADJ GND TA VPL-CS7 VPL-ES2 C705 0.47uF XX 11V D701 D1FS4A-TA XX D702 MA111-TX XX IC703 PQ20WZ1U XX Q701 SI4425DY-T1 XX R704 2.2k XX 1/10W CHIP R705 4.7k XX 1/10W CHIP R706 2.2k XX 1/10W CHIP R707 4.7k XX 1/10W CHIP R708 10k XX 1/10W CHIP R709 150 XX 1W RS R710 150 XX 1W RS SA S501 1 2 3 1 2 3 4 5 6 7 7P CN501 M+ M- T1 T2 T3 MOTOR- MOTOR+ 10k RV501 1 3 2 1SR154-400TE-25 D502 RECT 1 2 S502 1 2 3 1SR154-400TE-25 D501 RECT 1 2 S 1 2 3 4 4P CN60 SUB 3.3V LAMP TEMP LAMP COVER GND S60 TH60 LAMP_TEMP 16V 0.01 B C60 1/16W RN-CP 4.7k R60 V w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com VPL-CS7/ES2 6-20 6-20 Frame Wiring Frame Wiring 1 DC+ 2 NC 3 DC- LAMP ON LAMP ON COM COM AC(N) DC+ 1 2 3 4 5 6 7 8 9 1 2 3 4 5 1 2 3 4 5 1 2 3 4 5 6 1 2 3 4 1 2 3 4 1 2 3 4 5 1 2 3 4 5 1 2 3 4 1 2 3 1 2 3 1 2 3 1 2 3 1 2 3 4 1 2 3 4 5 1 2 3 4 5 1 2 3 4 5 6 7 8 9 10 11 12 1 2 3 1 2 3 4 5 4 5 6 7 8 9 10 11 12 1 2 3 4 5 6 7 8 9 A_COM COM FG N CHASSIS GND 3 L 1 2 3 1 2 NC NC LAMP_CONT LAMP_CONT AC(L) CN101 CN102 CN201 CN1 CN601 DC- HI/LO HI/LO PCONT D3.3V D3.3V FAN CONT1 PPROT GND POWER LED POWER LED GND FAN+B SUB3.3V SUB3.3V FAN+B GND KEY4 KEY4 GND SUB 5V 10 KEY0 KEY0 GND 11 GND GND 12 GND D3.3V D3.3V POWER LED POWER LED SUB3.3V SUB3.3V KEY4 KEY4 KEY0 KEY0 GND GND 6V 13 6V 14 GND 15 GND 16 D3.3V 17 SUB 5V D3.3V 18 SUB 5V CIRCS GND 19 CIRCS GND GND 20 GND 17V 21 LED VCC 17V 22 LED CONT GND 23 NC 17V GND PCONT FAN CONT1 PPROT GND GND FAN+B FAN+B GND GND SUB 5V GND GND 6V 6V GND GND D3.3V D3.3V GND GND 17V 17V GND GND 24 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 L CONT TF_OUT SUB 3.3V TF_IN LAMP TEMP LAMP COVER GND SUB 3.3V LAMP TEMP LAMP COVER GND SP+ SP- M+ M- T1 T2 T3 M+ M- T1 T2 T3 OUT_R GND CN904 CN906 CN806 CN804 CN807 CN805 CN10 CN80 CN70 CN60 CN501 CN701 CN702 CN803 CN802 CN905 CN903 CN815 CN811 CN810 CN812 CN809 OUT_G GND 3.3V-2 OUT_B TILT_X GND TILT_Y OUT_H GND OUT_V TA 3.3V-2 TILT_X TILT_Y GND TA GND IO_R GND IO_G GND IO_B GND OUT_H OUT_V GND GND GND GND GND GND GND R-Y B-Y Y GND 1 FAN+B FAN_PROT2A FAN_2A GND FAN_PROT2B FAN_2B GND FAN+B FAN_PROT2B FAN_2A 2 3 4 5 6 7 8 9 AC_INLET G Board (Power Supply) C Board BALLAST NR Board V Board L Board FPC Cable 24P mm H Board S Board Thermo Fuse Speaker SA Board Q Board Monitor_Out VPL-CS7 VPL-ES2 QA Board Component_In Fan 60 mm dia. Suction sirocco Suction sirocco 1 2 3 4 5 6 7 8 9 1 2 1 2 1 2 3 4 5 6 7 8 9 FPC Cable 24P mm GND FAN_PROT2B FAN_2B GND FAN_PROT1 FAN_1 GND FAN_PROT3 FAN_3 Fan 70 mm dia. D70 (LED) NSCW215T LOGO_LED Frame Wiring w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com VPL-CS7/ES2 7-1 7-1 Section 7 Board Layouts Index Board Name Page C 7-2 G 7-4 H 7-5 L 7-5 NR 7-5 QA (VPL-ES2) 7-5 Q (VPL-CS7) 7-5 SA 7-6 S 7-7 V 7-7 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com VPL-CS7/ES2 SAFETY CHECK-OUT After correcting the original service problem, perform the following safety checks before releasing the set to the customer : Check the metal trim, “metallized” knobs, screws, and all other exposed metal parts for AC leakage. Check leakage as described below. LEAKAGE TEST The AC leakage from any exposed metal part to earth ground and from all exposed metal parts to any exposed metal part having a return to chassis, must not exceed 0.5 mA. Leakage current can be measured by any one of three methods. 1. A commercial leakage tester, such as the Simpson 229 or RCA WT-540A. Follow the manufacturers’ instructions to use these instruments. 2. A battery-operated AC milliammeter. The Data Precision 245 digital multimeter is suitable for this job. 3. Measuring the voltage drop across a resistor by means of a VOM or battery-operated AC voltmeter. The “limit” indication is 0.75 V, so analog meters must have an accurate low- voltage scale. The Simpson 250 and Sanwa SH-63Trd are examples of a passive VOM that is suitable. Nearly all battery operated digital multimeters that have a 2 V AC range are suitable. (See Fig. A) To Exposed Metal Parts on Set Fig A. Using an AC voltmeter to check AC leakage. AC voltmeter (0.75V) Earth Ground 0.15 µF 1.5 kZ www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com Printed in Japan Sony Corporation 2004. 8 22 B&P Company ©2004 VPL-CS7 (SY) VPL-ES2 (SY) E 9-968-062-01 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com
