CD/DVD PLAYER SERVICE MANUAL Photo : DVP-NS15 DVP-NS15/NS51P/NS43P/NS53P/K56P RMT-D175A AEP Model UK Model DVP-NS15 Chinese Model DVP-NS51P Argentina Model Brazilian Model DVP-NS43P/NS53P Singapore Model Saudi Arabia Model DVP-NS51P/K56P Mexican Model E Model DVP-NS53P Russian Model DVP-K56P Taiwan Model DVP-K56P/NS51P Australian/New Zealand Mode India Model IND,PAK,MAR Model Iran Model Middle East Model Korean Model Malaysian Model Hong Kong Model Vietnam Model DVP-NS51P Photo : DVP-NS43P/NS53P RMT-D175A RMT-D175P This manual have three different type of DVD player appearance/structure . Please take note. Notes: Australia/NZ model only Photo : DVP-K56P Photo : DVP-NS51P /RMT-D175C/RMT-D175P www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 2 – DVP-NS15/NS51P/NS43P/NS53P/K56P System Laser: Semiconductor laser Signal format system: PAL/NTSC: (others) Signal format system: NTSC: (DVP-NS43P/NS53P only) Audio characteristics Frequency response: DVD VIDEO (PCM 48 kHz): 2 Hz to 22 kHz (±0.5 dB)/CD: 2 Hz to 20 kHz (±0.5 dB) Harmonic distortion: 0.01% Dynamic range: DVD VIDEO: 85 dB/CD: 85 dB Wow and flutter: Less than detected value (±0.001% W PEAK) Outputs (DVP-NS15 only) (Jack name: Jack type/Output level/ Load impedance) DIGITAL OUT (COAXIAL): Phono jack/ 0.5 Vp-p/75 ohms LINE (RGB)-TV: (AUDIO): SCART jack/2 Vrms/10 kilohms (VIDEO): SCART jack/1.0 Vp-p/75 ohms (S VIDEO): SCART jack/Y: 1.0 Vp-p, C: 0.3 Vp-p (PAL), 0.286 Vp-p (NTSC)/75 ohms (RGB): SCART jack/0.7 Vp-p/75 ohms Outputs and Input (DVP-NS51P/K56P) (Jack name: Jack type/Output level/ Load impedance) LINE OUT (AUDIO): Phono jack/2 Vrms/ 10 kilohms DIGITAL OUT (OPTICAL): Optical output jack/–18 dBm (wave length 660 nm) DIGITAL OUT (COAXIAL): Phono jack/ 0.5 Vp-p/75 ohms COMPONENT VIDEO OUT (Y, PB/CB, PR/CR): Phono jack/Y: 1.0 Vp-p, PB/CB, PR/CR: 0.7 Vp-p/75 ohms LINE OUT (VIDEO): Phono jack/1.0 Vp-p/75 ohms S VIDEO OUT: 4-pin mini DIN/Y: 1.0 Vp-p, C: 0.3 Vp-p (PAL), 0.286 Vp-p (NTSC)/75 ohms MIC Input: Phono jack (DVP-K56P only) Outputs (DVP-NS43P/NS53P) (Jack name: Jack type/Output level/ Load impedance) LINE OUT (AUDIO): Phono jack/2 Vrms/ 10 kilohms DIGITAL OUT (OPTICAL): (DVP-NS53P: AR2, BR4) Optical output jack/–18 dBm (wave length 660 nm) DIGITAL OUT (COAXIAL): Phono jack/ 0.5 Vp-p/75 ohms COMPONENT VIDEO OUT (Y, PB, PR): Phono jack/Y: 1.0 Vp-p/PB,PR: interlace*1 = 0.648 Vp-p, progressive or interlace*2 = 0.7 Vp-p/75 ohms *1 BLACK LEVEL (COMPONENT OUT) is ON *2 BLACK LEVEL (COMPONENT OUT) is OFF LINE OUT (VIDEO): Phono jack/1.0 Vp-p/75 ohms S VIDEO OUT: 4-pin mini DIN/Y: 1.0 Vp-p, C: 0.286 Vp-p/75 ohms SPECIFICATIONS General Power requirements: 120 V AC, 60 Hz (DVP-NS53P: MX only) 110 V AC, 60 Hz (NS51P:TW/K56P:TW) 110 – 240 V AC, 50/60 Hz (DVP-K56P: Except TW,RUS/ DVP-NS43P/NS53P: Except MX/ NS51P: Except TW) 220 – 240 V AC, 50/60 Hz (DVP-NS15/K56P:RUS only) See page 2 for further information. Power consumption: 9W (DVP-K56P/NS43P/NS53P/NS51P) 8W (DVP-NS15) Dimensions (approx.): 430 × 43 × 214.4 mm (DVP-K56P only) (width/height/depth) incl. projecting parts 430 × 43 × 207 mm (DVP-NS15) 430 × 43 × 208.8 mm (DVP-NS51P) (width/height/depth) incl. projecting parts 430 × 43 × 208 mm (DVP-NS43P/NS53P) (width/height/depth) incl. projecting parts Mass (approx.): 1.78 kg (DVP-NSK56P) 1.69 kg (DVP-NS15) 1.74 kg (DVP-NS51P) 1.72 kg (DVP-NS43P/NS53P) Operating temperature: 5°C to 35°C Operating humidity: 25% to 80% Supplied accessories See page 14. Specifications and design are subject to change without notice. (DVP-NS51P: AUS ONLY) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 3 – DVP-NS15/NS51P/NS43P/NS53P/K56P SAFETY CHECK-OUT 1. Check the area of your repair for unsoldered or poorly-soldered connections. Check the entire board surface for solder splashes and bridges. 2. Check the interboard wiring to ensure that no wires are “pinched” or contact high-wattage resistors. 3. Look for unauthorized replacement parts, particularly transistors, that were installed during a previous repair. Point them out to the customer and recommend their replacement. 4. Look for parts which, though functioning, show obvious signs of deterioration. Point them out to the customer and recommend their replacement. 5. Check the line cord for cracks and abrasion. Recommend the replacement of any such line cord to the customer. 6. Check the B+ voltage to see it is at the values specified. 7. Check the antenna terminals, metal trim, “metallized” knobs, screws, and all other exposed metal parts for AC leakage. Check leakage as described below. WARNING!! WHEN SERVICING, DO NOT APPROACH THE LASER EXIT WITH THE EYE TOO CLOSELY. IN CASE IT IS NECESSARY TO CONFIRM LASER BEAM EMISSION, BE SURE TO OBSERVE FROM A DISTANCE OF MORE THAN 25 cm FROM THE SURFACE OF THE OBJECTIVE LENS ON THE OPTICAL PICK-UP BLOCK. CAUTION: The use of optical instrument with this product will increase eye hazard. CAUTION Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure. SAFETY-RELATED COMPONENT WARNING!! COMPONENTS IDENTIFIED BY MARK OR DOTTED LINE WITH MARK ON THE SCHEMATIC DIAGRAMS AND IN THE PARTS LIST ARE CRITICAL TO SAFE OPERATION. REPLACE THESE COMPONENTS WITH SONY PARTS WHOSE PART NUMBERS APPEAR AS SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUBLISHED BY SONY. After correcting the original service problem, perform the following safety checks before releasing the set to the customer: LEAKAGE TEST The AC leakage from any exposed metal part to earth ground and from all exposed metal parts to any exposed metal part having a return to chassis, must not exceed 0.5mA (500 microampers). Leakage current can be measured by any one of three methods. 1. A commercial leakage tester, such as the Simpson 229 or RCA TW-540A. Follow the manufacturers’ instructions to use these instruments. 2. A battery-operated AC milliammeter. The Data Precision 245 digital multimeter is suitable for this job. 3. Measuring the voltage drop across a resistor by means of a VOM or battery-operated AC volmeter. The “limit” indication is 0.75V, so analog meters must have an accurate low voltage scale. The Simpson 250 and Sanwa SH-63Trd are examples of a passive VOM that is suitable. Nearly all battery operated digital multimeters that have a 2V AC range are suitable. (See Fig. A) Unleaded solder Boards requiring use of unleaded solder are printed with the lead-free mark (LF) indicating the solder contains no lead. (Caution: Some printed circuit boards may not come printed with the lead free mark due to their particular size.) : LEAD FREE MARK Unleaded solder has the following characteristics. • Unleaded solder melts at a temperature about 40°C highter than ordinary solder. Ordinary soldering irons can be used but the iron tip has to be applied to the solder joint for a slightly longer time. Soldering irons using a temperature regulator should be set to about 350°C Caution: The printed pattern (copper foil) may peel away if the heated tip is applied for too long, so be careful! • Strong viscosity Unleaded solder is more viscous (sticky, less prone to flow) than ordinary solder so use caution not to let solder bridges occur such as on IC pins, etc. • Usable with ordinary solder It is best to use only unleaded solder but unleaded solder may also be added to ordinary solder. ATTENTION AU COMPOSANT AYANT RAPPORT À LA SÉCURITÉ! LES COMPOSANTS IDENTIFÉS PAR UNE MARQUE SUR LES DIAGRAMMES SCHÉMATIQUES ET LA LISTE DES PIÈCES SONT CRITIQUES POUR LA SÉCURITÉ DE FONCTIONNEMENT. NE REMPLACER CES COMPOSANTS QUE PAR DES PIÈSES SONY DONT LES NUMÉROS SONT DONNÉS DANS CE MANUEL OU DANS LES SUPPÉMENTS PUBLIÉS PAR SONY. To Exposed Metal Parts on Set 0.15 F 1.5k AC Voltmeter (0.75 V) Earth Ground Fig.A. Using an Acvoltmeter to check AC leakage. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 4 – DVP-NS15/NS51P/NS43P/NS53P/K56P TABLE OF CONTENTS SERVICE NOTE 1. Disc Removal Procedure (at POWER OFF) ....................... 5 1. GENERAL WARNING ............................................................................ 1-1 Notes About the Discs ........................................................ 1-1 Precautions.......................................................................... 1-1 About This Manual ............................................................... 1-1 This Player Can Play the Following Discs......................... 1-1 Index to Parts and Controls ............................................... 1-2 Guide to the Control Menu Display .................................... 1-3 Hookups ...................................................................................... 1-3 Hooking Up the Player ........................................................ 1-3 Step 1: Unpacking ............................................................... 1-3 Step 2: Inserting Batteries into the Remote ....................... 1-3 Step 3: Connecting the Video Cords .................................. 1-4 Step 4: Connecting the Audio Cords .................................. 1-4 Step 5: Connecting the Mains Lead ................................... 1-5 Step 6: Quick Setup ............................................................ 1-5 Playing Discs ............................................................................... 1-5 Playing Discs ....................................................................... 1-5 Resuming Playback from the Point Where You Stopped the Disc (Multi-disc Resume) ........................ 1-6 Using the DVD's Menu ........................................................ 1-6 Selecting “ORIGINAL” or “PLAY LIST” on a DVD-RW/DVD-R ............................................................. 1-6 Playing VIDEO CD's With PBC Functions (PBC Playback) .............................................................. 1-6 Various Play Mode Functions (Programme Play, Shuffle Play, Repeat Play, A-B Repeat Play ................. 1-7 Searching for a Scene ................................................................ 1-8 Searching for a Particular Point on a Disc (Scan, Slow-motion Play, Freeze Frame) .................... 1-8 Searching for a Title/Chapter/Track/Scene, etc. ............... 1-8 Searching by Scene (PICTURE NAVIGATION) ............... 1-8 Viewing Information About the Disc ........................................... 1-9 Checking the Playing Time and Remaining Time .............. 1-9 Sound Adjustments ..................................................................... 1-9 Changing the Sound............................................................ 1-9 TV Virtual Surround Settings (TVS) ................................. 1-10 Enjoying Movies ........................................................................ 1-10 Changing the Angles ......................................................... 1-10 Displaying the Subtitles..................................................... 1-10 Adjusting the Playback Picture (CUSTOM PICTURE MODE) ..................................... 1-10 Sharpening the Picture (SHARPNESS) ........................... 1-11 Enjoying MP3 Audio and JPEG Images .................................. 1-11 About MP3 Audio Tracks and JPEG Image Files ........... 1-11 Playing MP3 Audio Tracks and JPEG Image Files ......... 1-11 Enjoying JPEG Images as a Slide Show ......................... 1-12 Using Various Additional Functions.......................................... 1-13 Locking Discs (CUSTOM PARENTAL CONTROL, PARENTAL CONTROL) .............................................. 1-13 Controlling Your TV with the Supplied Remote ................. 1-13 Settings and Adjustments......................................................... 1-14 Using the Setup Display ................................................... 1-14 Setting the Display or Sound Track Language (LANGUAGE SETUP) ................................................. 1-14 Settings for the Display (SCREEN SETUP) .................... 1-14 Custom Settings (CUSTOM SETUP) .............................. 1-15 Settings for the Sound (AUDIO SETUP) ......................... 1-15 Additional Information ................................................................ 1-15 Troubleshooting ................................................................. 1-15 Self-diagnosis Function (When letters/ numbers appear in the display .................................... 1-16 Glossary ............................................................................ 1-16 Specifications..................................................................... 1-17 2. DISASSEMBLY 2-1. Upper Case ......................................................................... 2-1 2-2. Front Panel Assembly......................................................... 2-1 2-3. Loading Assembly ............................................................... 2-3 2-4. Optical Pick-Up (Device, Optical KHM-313CAA/C2RP) ........................ 2-5 2-5. Rear Panel, MV Board and IF Board ................................. 2-6 2-6. Switching Regulator ............................................................ 2-9 2-7. Interval Views ..................................................................... 2-10 2-8. Circuit Boards Location..................................................... 2-11 3. BLOCK DIAGRAMS 3-1. Overall Block Diagram ........................................................ 3-1 3-2. Power Line Block Diagram ................................................. 3-3 3-3. System Control/Signal Processor (1) Block Diagram ...... 3-5 3-4. System Control/Signal Processor (2) Block Diagram ...... 3-7 3-5. RF/Servo Block Diagram .................................................... 3-9 3-6. Video (1) Block Diagram ................................................... 3-11 3-7. Video (2) Block Diagram ................................................... 3-13 3-8. Audio (1) Block Diagram ................................................... 3-15 3-9. Audio (2) Block Diagram ................................................... 3-17 3-10. Interface Control (1) Block Diagram ................................ 3-19 3-11. Interface Control (2) Block Diagram ................................ 3-21 4. PRINTED WIRING BOARDS AND SCHEMATIC DIAGRAMS 4-1. Frame Schematic Diagram ................................................. 4-1 4-2. Printed Wiring Boards and Schematic Diagrams .............. 4-3 • Waveforms MV-48 Board (DVP-NS15 only) ..................................... 4-4 MV-47 Board (Except DVP-NS15) ................................ 4-5 • IF-143 Printed Wiring Board .......................................... 4-7 • IF-143 (Interface) Schematic Diagram ........................ 4-9 • IF-144 Printed Wiring Board ........................................ 4-11 • IF-144 (Interface) Schematic Diagram ...................... 4-13 • IF-145 Printed Wiring Board ........................................ 4-15 • IF-145 (Interface) Schematic Diagram ...................... 4-17 • MC-161 Printed Wiring Board ..................................... 4-19 • MC-161 (MIC-ECHO) Schematic Diagram ................ 4-21 • MS-203 Printed Wiring Board ...................................... 4-23 • MS-203 (Loading Motor) Schematic Diagram............ 4-23 • MV-47 Printed Wiring Board ........................................ 4-25 • MV-47 (CPU, Servo-DSP, AVDEC) Schematic Diagram...................................................... 4-27 • MV-47 (Drive) Schematic Diagram ............................. 4-29 • MV-47 (Video) Schematic Diagram ............................. 4-31 • MV-47 (Audio) Schematic Diagram ............................. 4-33 • MV-47 (Power) Schematic Diagram ............................ 4-35 • MV-48 Printed Wiring Board ........................................ 4-37 • MV-48 (CPU, Servo-DSP, AVDEC) Schematic Diagram...................................................... 4-39 • MV-48 (Drive) Schematic Diagram ............................. 4-41 • MV-48 (Video D-EURO) Schematic Diagram ............ 4-43 • MV-48 (Audio_EURO) Schematic Diagram ............... 4-45 • MV-48 (Power) Schematic Diagram ............................ 4-47 • SW-467 Printed Wiring Board ..................................... 4-49 • SW-467 (Switch PWB) Schematic Diagram ............... 4-49 • SW-468 Printed Wiring Board ..................................... 4-51 • SW-468 (Switch) Schematic Diagram ........................ 4-51 • SW-469 Printed Wiring Board ..................................... 4-53 • SW-469 (Switch Board) Schematic Diagram ............. 4-53 • SW-475 Printed Wiring Board ..................................... 4-55 • SW-475 (Switch) Schematic Diagram ........................ 4-55 • Power Block (SRV1872WW) Printed Wiring Board .... 4-57 • Power Block (SRV1872WW) Schematic Diagram ..... 4-59 • Power Block (SRV1873UC) Printed Wiring Board ..... 4-61 • Power Block (SRV1873UC) Schematic Diagram ....... 4-63 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 5 – DVP-NS15/NS51P/NS43P/NS53P/K56P 5. IC PIN FUNCTION DESCRIPTION 5-1. System Control Pin Function (MV-47/78 Boards IC101) ................................................... 5-1 6. TEST MODE 6-1. Executing IOP Measurement ............................................. 6-1 6-2. Emergency History Check ................................................. 6-1 6-3. Initializing Setup Data .......................................................... 6-2 6-4. Version Information ............................................................. 6-3 6-5. If Con Self Diagnostic Function .......................................... 6-3 7. ELECTRICAL ADJUSTMENT 7-1. Power Supply Output Voltage Check ................................. 7-1 7-2. Adjustment of Video System (DVP-NS15) ......................... 7-2 7-3. Adjustment of Video System (Except DVP-NS15) ............ 7-4 8. REPAIR PARTS LIST 8-1. Exploded Views ................................................................... 8-1 8-1-1. Main Section ................................................................... 8-1 8-1-2. Mechanism Deck Assembly .......................................... 8-5 8-2. Electrical Parts List ............................................................. 8-6 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 6 – DVP-NS15/NS51P/NS43P/NS53P/K56P SERVICE NOTE 1. DISC REMOVAL PROCEDURE (at POWER OFF) 1) Open dust cover to access to a hole insert a tapering driver into the aperture of the unit bottom, and move the lever of chuck can in the direction of the arrow A. (See Fig. 1) 2) Draw out the tray in the direction of the arrow B, and remove a disc. (See Fig. 1) 3) After removing the disc, push in the direction of arrow C until the tray fully in. 4) Move the lever of chuck cam in the direction of arrow D. The lever of a chuck cam Hole Tray A D B C Fig. 1. – 6E – www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 1-1 DVP-NS15/NS51P/NS43P/NS53P/K56P 2 WARNING To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture. To avoid electrical shock, do not open the cabinet. Refer servicing to qualified personnel only. The mains lead must only be changed at a qualified service shop. CAUTION The use of optical instruments with this product will increase eye hazard. As the laser beam used in this CD/DVD player is harmful to eyes, do not attempt to disassemble the cabinet. Refer servicing to qualified personnel only. Disposal of Old Electrical & Electronic Equipment This symbol is applicable only in the European Union and other European countries with separate collection systems. Precautions Safety • The power requirements and power consumption of this unit are indicated on the back of the unit. Check that the unit’s operating voltage is identical with your local power supply. • To prevent fire or shock hazard, do not place objects filled with liquids, such as vases, on the apparatus. Installing • Do not install the unit in an inclined position. It is designed to be operated in a horizontal position only. • Keep the unit and discs away from equipment with strong magnets, such as microwave ovens, or large loudspeakers. • Do not place heavy objects on the unit. For Customers in Taiwan only Please recycle used batteries. DVP–XXXX 00V 00Hz 00W NO. 0-000-000-00 X Power requirements and power consumption m Notes About the Discs • To keep the disc clean, handle the disc by its edge. Do not touch the surface. • Do not expose the disc to direct sunlight or heat sources such as hot air ducts, or leave it in a car parked in direct sunlight as the temperature may rise considerably inside the car. • After playing, store the disc in its case. • Clean the disc with a cleaning cloth. Wipe the disc from the centre out. • Do not use solvents such as benzine, thinner, commercially available disc/lens cleaners, or anti-static spray intended for vinyl LPs. • If you have printed the disc’s label, dry the label before playing. 5 Enjoying MP3 Audio and JPEG Images . . . . . . . . . . . . . . . . . . . . . 45 About MP3 Audio Tracks and JPEG Image Files . . . . . . . . . . . . . . . . . . . . . 45 Playing MP3 Audio Tracks or JPEG Image Files. . . . . . . . . . . . . . . . . . . . . . 46 Enjoying JPEG Images as a Slide Show . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49 Using Various Additional Functions . . . . . . . . . . . . . . . . . . . . . . . 51 Locking Discs (CUSTOM PARENTAL CONTROL, PARENTAL CONTROL) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51 Controlling Your TV with the Supplied Remote . . . . . . . . . . . . . . . . . . . . . . . 54 Settings and Adjustments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56 Using the Setup Display. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56 Setting the Display or Sound Track Language (LANGUAGE SETUP) . . . . . 57 Settings for the Display (SCREEN SETUP). . . . . . . . . . . . . . . . . . . . . . . . . . 58 Custom Settings (CUSTOM SETUP). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59 Settings for the Sound (AUDIO SETUP) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60 Additional Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62 Self-diagnosis Function (When letters/numbers appear in the display). . . . . 65 Glossary. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65 Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67 Language Code List. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68 Parental Control Area Code List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68 Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69 About This Manual • Instructions in this manual describe the controls on the remote. You can also use the controls on the player if they have the same or similar names as those on the remote. • “DVD” may be used as a general term for DVD VIDEOs, DVD+RWs/DVD+Rs (+VR mode) and DVD-RWs/DVD-Rs (video mode). • The meaning of the icons used in this manual is described below: Icons Meaning Functions available for DVD VIDEOs and DVD+RWs/DVD+Rs in +VR mode or DVD-RWs/DVD-Rs in video mode Functions available for DVD-RWs/DVD-Rs in VR (Video Recording) mode Functions available for VIDEO CDs (including Super VCDs or CD-Rs/ CD-RWs in video CD format or Super VCD format) Functions available for music CDs or CD-Rs/CD-RWs in music CD format Functions available for DATA CDs (CD-ROMs/CD-Rs/CD-RWs containing MP3* audio tracks, and JPEG image files) Functions available for DATA DVDs (DVD-ROMs/DVD+RWs/ DVD+Rs/DVD-RWs/DVD-Rs containing MP3* audio tracks, and JPEG image files) * MP3 (MPEG-1 Audio Layer III) is a standard format defined by ISO (International Organization for Standardization)/IEC (International Electrotechnical Commission) MPEG which compresses audio data. 6 This Player Can Play the Following Discs “DVD+RW,” “DVD-RW,” “DVD+R,” “DVD-R,” “DVD VIDEO,” and “CD” logos are trademarks. Note about CDs/DVDs The player can play CD-ROMs/CD-Rs/CD- RWs recorded in the following formats: – music CD format – video CD format – MP3 audio tracks, JPEG image files of format conforming to ISO 9660* Level 1/ Level 2, or its extended format, Joliet – KODAK Picture CD format * A logical format of files and folders on CD- ROMs, defined by ISO (International Organization for Standardization). The player can play DVD-ROMs/ DVD+RWs/DVD-RWs/DVD+Rs/DVD-Rs recorded in the following format: – MP3 audio tracks and JPEG image files of format conforming to UDF (Universal Disk Format). Example of discs that the player cannot play The player cannot play the following discs: • CD-ROMs/CD-Rs/CD-RWs other than those recorded in the formats listed on this page. • CD-ROMs recorded in PHOTO CD format. • Data part of CD-Extras. • DVD Audio discs. • HD layer on Super Audio CDs. Also, the player cannot play the following discs: • A DVD VIDEO with a different region code. • A disc that has a non-standard shape (e.g., card, heart). • A disc with paper or stickers on it. • A disc that has the adhesive of cellophane tape or a sticker still left on it. Region code Your player has a region code printed on the back of the unit and only will play DVD VIDEOs (playback only) labelled with identical region codes. This system is used to protect copyrights. DVD VIDEOs labelled will also play on this player. If you try to play any other DVD VIDEO, the message “Playback prohibited by area limitations.” will appear on the TV screen. Depending on the DVD VIDEO, there may be no region code indication, even though playing the DVD VIDEO is prohibited by area restrictions. Format of discs DVD VIDEO DVD-RW/-R DVD+RW/+R VIDEO CD/ Music CD CD-RW/-R ALL DVP–XXXX 00V 00Hz 00W NO. 0-000-000-00 X Region code 3 Precautions On safety Should any solid object or liquid fall into the cabinet, unplug the player and have it checked by qualified personnel before operating it any further. On power sources • The player is not disconnected from the AC power source (mains) as long as it is connected to the wall outlet, even if the player itself has been turned off. • If you are not going to use the player for a long time, be sure to disconnect the player from the wall outlet. To disconnect the AC power cord (mains lead), grasp the plug itself; never pull the cord. On placement • Place the player in a location with adequate ventilation to prevent heat build-up in the player. • Do not place the player on a soft surface such as a rug. • Do not place the player in a location near heat sources, or in a place subject to direct sunlight, excessive dust, or mechanical shock. On operation • If the player is brought directly from a cold to a warm location, or is placed in a very damp room, moisture may condense on the lenses inside the player. Should this occur, the player may not operate properly. In this case, remove the disc and leave the player turned on for about half an hour until the moisture evaporates. • When you move the player, take out any discs. If you don’t, the disc may be damaged. On adjusting volume Do not turn up the volume while listening to a section with very low level inputs or no audio signals. If you do, the speakers may be damaged when a peak level section is played. On cleaning Clean the cabinet, panel, and controls with a soft cloth slightly moistened with a mild detergent solution. Do not use any type of abrasive pad, scouring powder or solvent such as alcohol or benzine. On cleaning discs, disc/lens cleaners Do not use a commercially available cleaning disc or disc/lens cleaner (wet or spray type). These may cause the apparatus to malfunction. If you have any questions or problems concerning your player, please consult your nearest Sony dealer. IMPORTANT NOTICE Caution: This player is capable of holding a still video image or on-screen display image on your television screen indefinitely. If you leave the still video image or on-screen display image displayed on your TV for an extended period of time you risk permanent damage to your television screen. Plasma display panel televisions and projection televisions are susceptible to this. SECTION 1 GENERAL This section is extracted from instruction manual. 2-665-997-11 Note: For IM part number used for other model, you can refer to accessories. (See page 8-11) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 1-2 DVP-NS15/NS51P/NS43P/NS53P/K56P 7 Notes • Notes about DVD+RWs/DVD+Rs, DVD-RWs/ DVD-Rs or CD-Rs/CD-RWs Some DVD+RWs/DVD+Rs, DVD-RWs/DVD- Rs, or CD-Rs/CD-RWs cannot be played on this player due to the recording quality or physical condition of the disc, or the characteristics of the recording device and authoring software. The disc will not play if it has not been correctly finalized. For more information, refer to the operating instructions for the recording device. Note that some playback functions may not work with some DVD+RWs/DVD+Rs, even if they have been correctly finalized. In this case, view the disc by normal playback. Also some DATA CDs/DATA DVDs created in Packet Write format cannot be played. • Music discs encoded with copyright protection technologies This product is designed to playback discs that conform to the Compact Disc (CD) standard. Recently, various music discs encoded with copyright protection technologies are marketed by some record companies. Please be aware that among those discs, there are some that do not conform to the CD standard and may not be playable by this product. • Note on DualDiscs A DualDisc is a two sided disc product which mates DVD recorded material on one side with digital audio material on the other side. However, since the audio material side does not conform to the Compact Disc (CD) standard, playback on this product is not guaranteed. Note on playback operations of DVDs and VIDEO CDs Some playback operations of DVDs and VIDEO CDs may be intentionally set by software producers. Since this player plays DVDs and VIDEO CDs according to the disc contents the software producers designed, some playback features may not be available. Also, refer to the instructions supplied with the DVDs or VIDEO CDs. Copyrights This product incorporates copyright protection technology that is protected by U.S. patents and other intellectual property rights. Use of this copyright protection technology must be authorized by Macrovision, and is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision. Reverse engineering or disassembly is prohibited. 8 Index to Parts and Controls For more information, see the pages indicated in parentheses. Front panel A [/1 (on/standby) button (22) B Disc tray (22) C Front panel display (9) D PROGRESSIVE indicator (17) Lights up when the player outputs progressive signals. E PROGRESSIVE button (17) F A (open/close) button (22) G H (play) button (22) H x (stop) button (23) I (remote sensor) (14) Rear panel A DIGITAL OUT (COAXIAL) jack (18) B LINE OUT L/R (AUDIO) jacks (18) C LINE OUT (VIDEO) jack (15) D S VIDEO OUT jack (15) E COMPONENT VIDEO OUT jacks (15) F DIGITAL OUT (OPTICAL) jack (18) 9 Front panel display When playing back a DVD VIDEO/DVD-VR mode disc When playing back a VIDEO CD with Playback Control (PBC) (26) When playing back a CD, DATA CD (MP3 audio)/DATA DVD (MP3 audio), or VIDEO CD (without PBC) * When playing DATA DVDs, the DVD indicator is displayed. When playing VIDEO CDs (without PBC), the VCD indicator is displayed. Current title/chapter or playing time (35) Disc type Current audio signal (39) Lights up when you can change the angle (41) Lights up during Repeat Play (29) Playing status Disc type Current scene or playing time (35) Playing status Lights up during A-B Repeat Play (30) Playing time (35) Disc type* Current track (35) Lights up during Repeat Play (29) Lights up when playing MP3 audio tracks (45) Playing status ,continued 10 Remote A TV [/1 (on/standby) button (54) B Z OPEN/CLOSE button (23) C Number buttons (25) The number 5 button has a tactile dot.* D CLEAR button (27) E TOP MENU button (25) F C/X/x/c buttons (25) G O RETURN button (22, 23) H / REPLAY/STEP/ ADVANCE/STEP buttons (23, 31) I ./> PREV/NEXT (previous/ next) buttons (23) J m/M SCAN/SLOW buttons (31) K ZOOM button (23, 48) L SLOW PLAY/FAST PLAY buttons (23) M /AUDIO button (38) N /SUBTITLE button (41) O [/1 (on/standby) button (22) P 2/VOL (volume) +/– buttons (54) The + button has a tactile dot.* Q t/TV/VIDEO button (54) R PICTURE NAVI (picture navigation) button (33, 48) S TIME/TEXT button (35) T MENU button (25) U ENTER button (20) V DISPLAY button (11) W H/PLAY button (22) The H button has a tactile dot.* X x STOP button (23) Y X PAUSE button (23) Z SUR (surround) button (39) wj /ANGLE button (41) * Use the tactile dot as a reference when operating the player. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 1-3 DVP-NS15/NS51P/NS43P/NS53P/K56P 11 Guide to the Control Menu Display Use the Control Menu to select a function and to view related information. Press DISPLAY repeatedly to turn on or change the Control Menu display as follows: Control Menu display The Control Menu display 1 and 2 will show different items depending on the disc type. For details about each item, see the pages in parentheses. Example: Control Menu display 1 when playing a DVD VIDEO. *1 Displays the scene number for VIDEO CDs (PBC is on), track number for VIDEO CDs/CDs, album number for DATA CDs/DATA DVDs. *2 Displays the index number for VIDEO CDs, MP3 audio track number or JPEG image file number for DATA CDs/DATA DVDs. *3 Displays Super VCD as “SVCD.” *4 Displays the date for JPEG files. To turn off the display Press DISPLAY. Control Menu display 1 m Control Menu display 2 (Only for DATA CDs/DATA DVDs) m Control Menu display off , OFF OFF SET ON PLAY 1 8 ( 3 4 ) 1 2 ( 2 7 ) T 1 : 3 2 : 5 5 DVD VIDEO Quit: PROGRAM ENTER DISPLAY Currently playing chapter number*2 Playing time*4 Total number of chapters*2 Options Current setting Total number of titles*1 Playback status (N Playback, X Pause, x Stop, etc.) Function name of selected Control Menu item Operation message Selected item Control Menu items Type of disc being played*3 Currently playing title number*1 ,continued 12 List of Control Menu items Item Item Name, Function TITLE (page 32)/SCENE (page 32)/TRACK (page 32) Selects the title, scene, or track to be played. CHAPTER (page 32)/INDEX (page 32) Selects the chapter or index to be played. TRACK (page 32) Selects the track to be played. ORIGINAL/PLAY LIST (page 25) Selects the type of titles (DVD-RW/DVD-R in VR mode) to be played, the ORIGINAL one, or an edited PLAY LIST. TIME/TEXT (page 32) Checks the elapsed time and the remaining playback time. Input the time code for picture and music searching. Displays the DVD/CD text, or the DATA CD/DATA DVD track or file name. PROGRAM (page 27) Selects the title, chapter, or track to play in the order you want. SHUFFLE (page 28) Plays the title, chapter, or track in random order. REPEAT (page 29) Plays the entire disc (all titles/all tracks/all albums) repeatedly or one title/chapter/track/ album repeatedly. A-B REPEAT (page 30) Specifies the parts you want to play repeatedly. CUSTOM PICTURE MODE (page 42) Adjusts the video signal from the player. You can select the picture quality that best suits the programme you are watching. SHARPNESS (page 44) Exaggerates the outline of the image to produce a sharper picture. PARENTAL CONTROL (page 51) Set to prohibit playback on this player. SETUP (page 56) QUICK Setup (page 20) Use Quick Setup to choose the desired language of the on-screen display, the aspect ratio of the TV and the audio output signal. CUSTOM Setup In addition to the Quick Setup setting, you can adjust various other settings. RESET Returns the settings in “SETUP” to the default setting. ALBUM (page 45) Selects the album that contains the MP3 audio tracks and JPEG image files to be played. FILE (page 32) Selects the JPEG image file to be played. DATE (page 48) Displays the date the picture was taken by a digital camera. INTERVAL (page 50) Specifies the duration for which the slides are displayed on the screen. EFFECT (page 50) Selects the effects to be used for changing slides during a slide show. 13 z Hint The Control Menu icon indicator lights up in green when you select any item except “OFF” (“PROGRAM,” “SHUFFLE,” “REPEAT,” “A-B REPEAT,” “CUSTOM PICTURE MODE,” “SHARPNESS” only). The “ORIGINAL/PLAY LIST” indicator lights up in green when you select “PLAY LIST” (default setting). MODE (MP3, JPEG) (page 49) Selects the data type; MP3 audio track (AUDIO), JPEG image file (IMAGE) or both (AUTO) to be played when playing a DATA CD or DATA DVD. t 14 Hookups Hooking Up the Player Follow steps 1 to 6 to hook up and adjust the settings of the player. Notes • Plug cords securely to prevent unwanted noise. • Refer to the instructions supplied with the components to be connected. • You cannot connect this player to a TV that does not have a video input jack. • Be sure to disconnect the mains lead of each component before connecting. Step 1: Unpacking Check that you have the following items: • Audio/Video cord (phono plug × 3 y phono plug × 3) (1) • Remote commander (remote) (1) • R6 (size AA) batteries (2) Step 2: Inserting Batteries Into the Remote You can control the player using the supplied remote. Insert two R6 (size AA) batteries by matching the 3 and # ends on the batteries to the markings inside the compartment. When using the remote, point it at the remote sensor on the player. Notes • Do not leave the remote in an extremely hot or humid place. • Do not drop any foreign object into the remote casing, particularly when replacing the batteries. • Do not expose the remote sensor to direct light from the sun or a lighting apparatus. Doing so may cause a malfunction. • If you do not use the remote for an extended period of time, remove the batteries to avoid possible damage from battery leakage and corrosion. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 1-4 DVP-NS15/NS51P/NS43P/NS53P/K56P 15 Hookups Step 3: Connecting the Video Cords Connect this player to your TV monitor, projector, or AV amplifier (receiver) using a video cord. Select one of the patterns A through C, according to the input jack on your TV monitor, projector, or AV amplifier (receiver). In order to view progressive signal (525p or 625p) pictures with a compatible TV, projector, or monitor, you must use pattern C. A If you are connecting to a video input jack Connect the yellow plug of an audio/video cord (supplied) to the yellow (video) jack. You will enjoy standard quality images. With this connection, select “LINE OUT/S VIDEO OUT” (default) by pressing the PROGRESSIVE button on the front panel. A VIDEO AUDIO INPUT L R C PR/CR PB/CB Y COMPONENT VIDEO IN B INPUT S VIDEO Audio/video cord (supplied) Component video cord (not supplied) (yellow) TV, projector, or AV amplifier (receiver) to S VIDEO OUT TV, projector, or AV amplifier (receiver) (green) S VIDEO cord (not supplied) TV, projector, or AV amplifier (receiver) (red) (green) (blue) (red) to LINE OUT (VIDEO) l : Signal flow CD/DVD player to COMPONENT VIDEO OUT (blue) (yellow) Yellow White (L) Red (R) Yellow White (L) Red (R) ,continued 16 B If you are connecting to an S VIDEO input jack Connect an S VIDEO cord (not supplied). You will enjoy high quality images. With this connection, select “LINE OUT/S VIDEO OUT” (default) by pressing the PROGRESSIVE button on the front panel. C If you are connecting to a monitor, projector, or AV amplifier (receiver) having component video input jacks (Y, PB/CB, PR/CR) Connect the component via the COMPONENT VIDEO OUT jacks using a component video cord (not supplied) or three video cords (not supplied) of the same kind and length. You will enjoy accurate colour reproduction and high quality images. If your TV accepts progressive 525p/625p format signals, use this connection and press the PROGRESSIVE button on the front panel to output progressive signals. For details, see “Selecting the video output jack and signal format (PROGRESSIVE button)” (page 17). When connecting to a standard 4:3 screen TV Depending on the disc, the image may not fit your TV screen. To change the aspect ratio, see page 58. To change the colour system If the on-screen menu of the player does not appear on the connected TV, switch the player’s colour system to match the colour system of the TV (NTSC or PAL). First turn off the player by pressing "/1, and then press "/1 again while holding down x on the player. The player turns back on, and the name of the colour system scrolls across the front panel display. Note Do not connect a VCR, etc., between your TV and the player. If you pass the player signals via the VCR, you may not receive a clear image on the TV screen. If your TV has only one audio/video input jack, connect the player to this jack. Green Blue Red Green Blue Red VCR CD/DVD player TV Connect directly 17 Hookups Selecting the video output jack and signal format (PROGRESSIVE button) By using the PROGRESSIVE button on the front panel, you can select the jack from which the player outputs Progressive or Interlace signals. The default setting will output Interlace signals from the LINE OUT(VIDEO) or S VIDEO OUT jacks. Press the button once to switch to the COMPONENT VIDEO OUT jacks. Each additional press of the button will change the output signal as shown below. Note that signals are not output from the COMPONENT VIDEO OUT jacks when “LINE OUT/ S VIDEO OUT” is selected, and signals are not output from the LINE OUT(VIDEO) or S VIDEO OUT jacks when any other setting is selected. ◆When your TV is connected to jack other than COMPONENT VIDEO OUT jacks (LINE OUT(VIDEO) or S VIDEO OUT), select: - “LINE OUT/S VIDEO OUT” ◆When your TV is connected to COMPONENT VIDEO OUT jacks, select: - “NORMAL (INTERLACE)” - “PROGRESSIVE AUTO” Normally select this if your TV is compatible with progressive signals. This automatically detects the software type, and selects the appropriate conversion method. - “PROGRESSIVE VIDEO” Select this if your TV is compatible with progressive signals and the image is not clear when you select PROGRESSIVE AUTO. This setting will fix the conversion method to PROGRESSIVE VIDEO for video based software. About DVD software types and the conversion method DVD software can be divided into two types: film-based software and video based software. Video-based software is derived from TV, such as dramas and sit-coms, and displays images at 30 frames/60 fields (25 frames/50 fields) per second. Film-based software is derived from film and displays images at 24 frames per second. Some DVD software contains both video and film. In order for these images to appear natural on your screen when output in progressive format, the progressive signals need to be converted to match the type of DVD software that you are watching. Notes • When you play video-based software in progressive signal format, sections of some types of images may appear unnatural due to the conversion process when output through the COMPONENT VIDEO OUT jacks. • Using the COMPONENT VIDEO OUT jacks will cause the picture to go blank. In this case, press the PROGRESSIVE button to see the picture. • When using LINE OUT (VIDEO) or S VIDEO OUT, the picture will go blank when your setting is “NORMAL (INTERLACE)”, or “PROGRESSIVE AUTO”, or “PROGRESSIVE VIDEO”. In this case, press the button repeatedly until you see the picture. Setting/Display Front Panel Display Output Connection “LINE OUT/S VIDEO OUT” LINE/S LINE OUT or S VIDEO OUT jacks “NORMAL (INTERLACE)” COMPONENT COMPONENT VIDEO OUT jacks “PROGRESSIVE AUTO” P AUTO COMPONENT VIDEO OUT jacks “PROGRESSIVE VIDEO” P VIDEO COMPONENT VIDEO OUT jacks 18 Step 4: Connecting the Audio Cords Select one of the following patterns A or B, according to the input jack on your TV monitor, projector, or AV amplifier (receiver). This will enable you to listen to sound. z Hint For correct speaker location, see the operating instructions supplied with the connected components. VIDEO AUDIO INPUT L R B A AV amplifier (receiver) with a decoder (red) TV, projector, or AV amplifier (receiver) Audio/video cord (supplied) : Signal flow Coaxial digital cord (not supplied) to DIGITAL OUT (COAXIAL or OPTICAL) to LINE OUT L/R (AUDIO) Optical digital cord (not supplied) Rear (L) CD/DVD player (white) (yellow)* (yellow)* (white) (red) [Speakers] Front (L) [Speakers] to coaxial digital input Rear (R) Front (R) Subwoofer or Centre * The yellow plug is used for video signals (page 15). to optical digital input www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 1-5 DVP-NS15/NS51P/NS43P/NS53P/K56P 19 Hookups A Connecting to audio L/R input jacks This connection will use your TV’s or stereo amplifier’s (receiver’s) two speakers for sound. Connect using the audio/video cord (supplied). • Surround effect (page 39) TV: Dynamic Theatre, Dynamic, Wide, Night Stereo amplifier (receiver): Standard, Night B Connecting to a digital audio input jack If your AV amplifier (receiver) has a Dolby Digital*1, DTS*2, or MPEG audio decoder and a digital input jack, use this connection. Connect using a coaxial or optical digital cord (not supplied). • Surround effect Dolby Digital (5.1ch), DTS (5.1ch), MPEG audio (5.1ch) *1 Manufactured under license from Dolby Laboratories. “Dolby,” “Pro Logic,” and the double-D symbol are trademarks of Dolby Laboratories. *2 “DTS” and “DTS Digital Out” are trademarks of Digital Theater Systems, Inc. Notes • After you have completed the connection, make the appropriate settings in Quick Setup (page 20). If your AV amplifier (receiver) has an MPEG audio decoder function, set “MPEG” to “MPEG” (page 61). Otherwise, no sound or a loud noise will come from your speakers. • The TVS effects of this player cannot be used with this connection. • In order to listen to DTS sound tracks, you must use this connection. DTS sound tracks are not output through the LINE OUT L/R (AUDIO) jacks, even if you set “DTS” to “ON” in Quick Setup (page 20). Yellow White (L) Red (R) Yellow White (L) Red (R) Coaxial cord Optical cord 20 Step 5: Connecting the Mains Lead Plug the player and TV mains lead (power cord) into a mains. Step 6: Quick Setup Follow the steps below to make the minimum number of basic adjustments for using the player. To skip an adjustment, press >. To return to the previous adjustment, press .. The on- screen displays differ depending on the player model. Oceanian model is used for illustration unless otherwise specified. 1 Turn on the TV. 2 Press [/1. 3 Switch the input selector on your TV so that the signal from the player appears on the TV screen. “Press [ENTER] to run QUICK SETUP” (press enter to run Quick Setup) appears at the bottom of the screen. If this message does not appear, select “QUICK” (quick) under “SETUP” (setup) in the Control Menu to run Quick Setup (page 57). 4 Press ENTER without inserting a disc. The Setup Display for selecting the language used in the on-screen display appears. The available languages differ depending upon the player model. 5 Press X/x to select a language. The player displays the menu and subtitles in the selected language. ENTER LANGUAGE SETUP OSD: MENU: AUDIO: SUBTITLE: ITALIANO ESPAÑOL NEDERLANDS DANSK SVENSKA FRANÇAIS ENGLISH ENGLISH DEUTSCH 21 Hookups 6 Press ENTER. The Setup Display for selecting the aspect ratio of the TV to be connected appears. 7 Press X/x to select the setting that matches your TV type. ◆ If you have a wide-screen TV or a 4:3 standard TV with a wide-screen mode • 16:9 (page 58) ◆ If you have a 4:3 standard TV • 4:3 LETTER BOX or 4:3 PAN SCAN (page 58) 8 Press ENTER. The Setup Display for selecting the type of jack used to connect your amplifier (receiver) appears. 9 Press X/x to select the type of jack (if any) you are using to connect to an amplifier (receiver), then press ENTER. If you did not connect an AV amplifier (receiver), select “NO,” then go to step 13. If you connected an AV amplifier (receiver) using just an audio cord, select “YES: LINE OUTPUT L/R (AUDIO),” then go to step 13. If you connected an AV amplifier (receiver) using either a optical or coaxial digital cord, select “YES: DIGITAL OUTPUT.” 10Press X/x to select the type of Dolby Digital signal you wish to send to your amplifier (receiver). If your AV amplifier (receiver) has a Dolby Digital decoder, select “DOLBY DIGITAL.” Otherwise, select “D-PCM.” 11Press ENTER. “DTS” is selected. 12Press X/x to select whether or not you wish to send a DTS signal to your amplifier (receiver). If your AV amplifier (receiver) has a DTS decoder, select “ON.” Otherwise, select “OFF.” 13Press ENTER. Quick Setup is finished and connections are complete. If your AV amplifier (receiver) has an MPEG audio decoder, set “MPEG” to “MPEG” (page 61). SCREEN SETUP TV TYPE: 16:9 4:3 LETTER BOX 4:3 PAN SCAN FULL COLOR SYSTEM (VIDEO CD): BACKGROUND: SCREEN SAVER: 4:3 OUTPUT: 16:9 YES NO Is this player connected to an amplifier (receiver) ? Select the type of jack you are using. LINE OUTPUT L/R (AUDIO) DIGITAL OUTPUT AUDIO SETUP AUDIO DRC: DIGITAL OUT: DOLBY DIGITAL: MPEG: STANDARD ON DOWNMIX: DOLBY SURROUND D-PCM DTS: DOLBY DIGITAL 48kHz/96kHz PCM: 48kHz/16bit D-PCM AUDIO SETUP AUDIO DRC: DIGITAL OUT: DOLBY DIGITAL: MPEG: STANDARD ON DOWNMIX: DOLBY SURROUND D-PCM PCM DTS: 48kHz/96kHz PCM: OFF OFF ON 22 Playing Discs Playing Discs Depending on the DVD or VIDEO CD, some operations may be different or restricted. Refer to the operating instructions supplied with your disc. 1 Turn on your TV. 2 Press [/1. The player turns on. 3 Switch the input selector on your TV so that the signal from the player appears on the TV screen. ◆ When using an amplifier (receiver) Turn on the amplifier (receiver) and select the appropriate channel so that you can hear sound from the player. 4 Press A on the player, and place a disc on the disc tray. 5 Press H. The disc tray closes. The player starts playback (continuous play). Adjust the volume on the TV or the amplifier (receiver). Depending on the disc, a menu may appear on the TV screen. For DVD VIDEOs, see page 25. For VIDEO CDs, see page 26. To turn off the player Press [/1. The player enters standby mode. z Hint You can have the player turn off automatically whenever you leave it in stop mode for more than 30 minutes. To turn this function on or off, set “AUTO POWER OFF” in “CUSTOM SETUP” to “ON” or “OFF” (page 59). Note Discs created on DVD recorders must be correctly finalized before they can be played. For more information about finalizing, refer to the operating instructions supplied with the DVD recorder. Notes on playing DTS sound tracks on a DVD VIDEO • DTS audio signals are output only through the DIGITAL OUT (COAXIAL or OPTICAL) jack. • When you play a DVD VIDEO with DTS sound tracks, set “DTS” to “ON” in “AUDIO SETUP” (page 61). • If you connect the player to audio equipment without a DTS decoder, do not set “DTS” to “ON” in “AUDIO SETUP” (page 61). A loud noise may come out from the speakers, affecting your ears or causing the speakers to be damaged. ENTER RETURN Playback side facing down www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 1-6 DVP-NS15/NS51P/NS43P/NS53P/K56P 23 Playing Discs Additional operations *1 DVD VIDEOs/DVD-RWs/DVD-Rs only *2 DVD VIDEOs/DVD-RWs/DVD-Rs/ DVD+RWs/DVD+Rs only *3 Video and JPEG pictures only (except BACKGROUND pictures). You can move the enlarged picture using C/X/x/c. Depending upon the contents of the disc, the zoom function may be canceled automatically when the picture is moved. Note You may not be able to use the Replay or Advance function with some scenes. Playback quickly or slowly with sound You can listen to dialogue or sound while playing the current scene quickly or slowly. During playback, press FAST PLAY or SLOW PLAY. The speed changes when you press either FAST PLAY or SLOW PLAY. To return to normal playback Press H. Notes • You can only use this function with DVDs/ VIDEO CDs/Super VCDs and DVD-RWs/DVD- Rs in VR mode only. • “Operation not possible” will appear when maximum or minimum speed is reached. • During Fast Play or Slow Play mode, you cannot change the angle (page 41), subtitle (page 41) and sound (page 38). The sound can only be changed for VIDEO CDs/Super VCDs. • Fast Play and Slow Play functions do not work when playing DTS sound tracks. • You cannot use Fast Play or Slow Play function when playing a still picture on DVD-RW/DVD-R in VR mode. Locking the disc tray (Child Lock) You can lock the disc tray to prevent children from opening it. When the player is in standby mode, press O RETURN, ENTER, and then [/1 on the remote. The player turns on and “LOCKED” appears on the front panel display. The A and Z buttons on the player or the remote do not work while the Child Lock is set. To unlock the disc tray When the player is in standby mode, press O RETURN, ENTER, and then [/1 again. Note Even if you select “RESET” under “SETUP” in the Control Menu (page 57), the disc tray remains locked. To Operation Stop Press x Pause Press X Resume play after pause Press X or H Go to the next chapter, track, or scene in continuous play mode Press > Go back to the previous chapter, track, or scene in continuous play mode Press . Stop play and remove the disc Press Z Replay the previous scene*1 Press REPLAY during playback Briefly fast forward the current scene*2 Press ADVANCE during playback Magnify the image*3 Press ZOOM repeatedly. Press CLEAR to cancel. CLEAR REPLAY ZOOM SLOW PLAY FAST PLAY ADVANCE 24 Resuming Playback From the Point Where You Stopped the Disc (Multi-disc Resume) The player stores the point where you stopped the disc for up to 6 discs and resumes playback the next time you insert the same disc. If you store a resume playback point for the seventh disc, the resume playback point for the first disc is deleted. 1 While playing a disc, press x to stop playback. “RESUME” appears on the front panel display. 2 Press H. The player starts playback from the point where you stopped the disc in step 1. z Hint To play from the beginning of the disc, press x twice, then press H. Notes • “MULTI-DISC RESUME” in “CUSTOM SETUP” must be set to “ON” (default) for this function to work (page 60). • The point where you stopped playing is cleared when: – you change the play mode. – you change the settings on the Setup Display. • For DVD-RWs/DVD-Rs in VR mode, CDs, DATA CDs, and DATA DVDs, the player remembers the resume playback point for the current disc. The resume point is cleared when: – you opened the disc tray. – you disconnect the mains lead. – the player enters standby mode (DATA CD/ DATA DVD only). • Resume Play does not work during Shuffle Play and Programme Play. • This function may not work with some discs. • If “MULTI-DISC RESUME” in “CUSTOM SETUP” is set to “ON” and you playback a recorded disc such as DVD-RW, the player may playback other recorded discs from the same resume point. 25 Playing Discs Using the DVD’s Menu A DVD is divided into long sections of a picture or a music feature called “titles.” When you play a DVD which contains several titles, you can select the title you want using the TOP MENU button. When you play DVDs that allow you to select items such as language for the sound and subtitles, select these items using the MENU button. 1 Press TOP MENU or MENU. The disc’s menu appears on the TV screen. The contents of the menu vary from disc to disc. 2 Press C/X/x/c or the number buttons to select the item you want to play or change. If you press the number buttons, the following display appears. Press the number buttons to select the item you want. 3 Press ENTER. Selecting “ORIGINAL” or “PLAY LIST” on a DVD- RW/DVD-R Some DVD-RWs/DVD-Rs in VR (Video Recording) mode have two types of titles for playback: originally recorded titles (ORIGINAL) and titles that can be created on recordable DVD players for editing (PLAY LIST). You can select the type of title to be played. 1 Press DISPLAY when the player is in stop mode. The Control Menu appears. 2 Press X/x to select (ORIGINAL/PLAY LIST), then press ENTER. The options for “ORIGINAL/PLAY LIST” appear. 3 Press X/x to select a setting. • PLAY LIST: plays the titles created from “ORIGINAL” for editing. • ORIGINAL: plays the titles originally recorded. 4 Press ENTER. ENTER MENU TOP MENU Number buttons 1 ENTER DISPLAY 1 8 ( 3 4 ) 1 2 ( 2 7 ) DVD-VR PLAY LIST PLAY LIST ORIGINAL T 1 : 3 2 : 5 5 26 Playing VIDEO CDs With PBC Functions (PBC Playback) PBC (Playback Control) allows you to play VIDEO CDs interactively by following the menu on the TV screen. 1 Start playing a VIDEO CD with PBC functions. The menu for your selection appears. 2 Press the number buttons to select the item number you want. 3 Press ENTER. 4 Follow the instructions in the menu for interactive operations. Refer to the instructions supplied with the disc, as the operating procedure may differ depending on the VIDEO CD. To return to the menu Press O RETURN. z Hint To play without using PBC, press ./> or the number buttons while the player is stopped to select a track, then press H or ENTER. “Play without PBC” appears on the TV screen and the player starts continuous play. You cannot play still pictures such as a menu. To return to PBC playback, press x twice then press H. Note Depending on the VIDEO CD, “Press ENTER” in step 3 may appear as “Press SELECT” in the instructions supplied with the disc. In this case, press H. ENTER RETURN Number buttons www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 1-7 DVP-NS15/NS51P/NS43P/NS53P/K56P 27 Playing Discs Various Play Mode Functions (Programme Play, Shuffle Play, Repeat Play, A-B Repeat Play) You can set the following play modes: • Programme Play (page 27) • Shuffle Play (page 28) • Repeat Play (page 29) • A-B Repeat Play (page 30) Note The play mode is cancelled when: – you open the disc tray. – the player enters standby mode by pressing [/1. Creating your own programme (Programme Play) You can play the contents of a disc in the order you want by arranging the order of the titles, chapters, or tracks on the disc to create your own programme. You can programme up to 99 titles, chapters, and tracks. 1 Press DISPLAY. The Control Menu appears. 2 Press X/x to select (PROGRAM), then press ENTER. The options for “PROGRAM” appear. 3 Press X/x to select “SET t,” then press ENTER. 4 Press c. The cursor moves to the title or track row “T” (in this case, “01”). 5 Select the title, chapter, or track you want to programme. ◆ When playing a DVD VIDEO For example, select chapter “03” of title “02.” Press X/x to select “02” under “T,” then press ENTER. CLEAR ENTER DISPLAY OFF OFF SET ON PLAY 1 8 ( 3 4 ) 1 2 ( 2 7 ) T 1 : 3 2 : 5 5 DVD VIDEO PROGRAM 1. TITLE ALL CLEAR 2. TITLE – – 3. TITLE – – 4. TITLE – – 5. TITLE – – 6. TITLE – – 7. TITLE – – T – – 01 02 03 04 05 “TRACK” is displayed when you play a VIDEO CD, or CD. Titles or tracks recorded on a disc PROGRAM 1. TITLE – – ALL CLEAR 2. TITLE – – 3. TITLE – – 4. TITLE – – 5. TITLE – – 6. TITLE – – 7. TITLE – – T C ALL 01 02 03 04 05 06 – – 02 03 04 05 01 Chapters recorded on a disc PROGRAM 1. TITLE – – ALL CLEAR 2. TITLE – – 3. TITLE – – 4. TITLE – – 5. TITLE – – 6. TITLE – – 7. TITLE – – C ALL 03 04 05 06 T – – 01 02 03 04 05 02 01 ,continued 28 Next, press X/x to select “03” under “C,” then press ENTER. ◆ When playing a VIDEO CD, or CD For example, select track “02.” Press X/x to select “02” under “T,” then press ENTER. 6 To programme other titles, chapters, or tracks, repeat steps 4 to 5. The programmed titles, chapters, and tracks are displayed in the selected order. 7 Press H to start Programme Play. Programme Play begins. When the programme ends, you can restart the same programme again by pressing H. To return to normal play Press CLEAR, or select “OFF” after step 2. To play the same programme again, select “ON” in step 3 and press ENTER. To change or cancel a programme 1 Follow steps 1 to 3 of “Creating your own programme (Programme Play).” 2 Select the programme number of the title, chapter, or track you want to change or cancel using X/x and press c. If you want to delete the title, chapter, or track from the programme, press CLEAR. 3 Follow step 5 for new programming. To cancel a programme, select “--” under “T,” then press ENTER. To cancel all of the titles, chapters, or tracks in the programmed order 1 Follow steps 1 to 3 of “Creating your own programme (Programme Play).” 2 Press X and select “ALL CLEAR.” 3 Press ENTER. z Hint You can perform Repeat Play or Shuffle Play of programmed titles, chapters, or tracks. During Programme Play, follow the steps of Repeat Play (page 29) or Shuffle Play (page 28). Notes • When you programme tracks on a Super VCD, the total playing time is not displayed. • You cannot use this function with VIDEO CDs and Super VCDs with PBC playback. Playing in random order (Shuffle Play) You can have the player “shuffle” titles, chapters, or tracks. Subsequent “shuffling” may produce a different playing order. 1 Press DISPLAY during playback. The Control Menu appears. 2 Press X/x to select (SHUFFLE), then press ENTER. The options for “SHUFFLE” appear. 3 Press X/x to select the item to be shuffled. ◆ When playing a DVD VIDEO • TITLE • CHAPTER ◆ When playing a VIDEO CD or CD • TRACK T – – 01 02 03 04 05 PROGRAM 1. TITLE 0 2 – 0 3 ALL CLEAR 2. TITLE – – 3. TITLE – – 4. TITLE – – 5. TITLE – – 6. TITLE – – 7. TITLE – – Selected title and chapter PROGRAM 1. TRACK 0 2 ALL CLEAR 2. TRACK – – 3. TRACK – – 4. TRACK – – 5. TRACK – – 6. TRACK – – 7. TRACK – – 0:15:30 – – 01 02 03 04 05 T Selected track Total time of the programmed tracks PLAY 1 8 ( 3 4 ) 1 2 ( 2 7 ) T 1 : 3 2 : 5 5 OFF CHAPTER TITLE OFF DVD VIDEO 29 Playing Discs ◆ When Programme Play is activated • ON: shuffles titles, chapters, or tracks selected in Programme Play. 4 Press ENTER. Shuffle Play starts. To return to normal play Press CLEAR, or select “OFF” in step 3. z Hints • You can set Shuffle Play while the player is stopped. After selecting the “SHUFFLE” option, press H. Shuffle Play starts. • Up to 200 chapters in a disc can be played in random order when “CHAPTER” is selected. Note You cannot use this function with VIDEO CDs or Super VCDs with PBC playback. Playing repeatedly (Repeat Play) You can play all of the titles or tracks on a disc, or a single title, chapter, or track repeatedly. You can use a combination of Shuffle or Programme Play modes. 1 Press DISPLAY during playback. The Control Menu appears. 2 Press X/x to select (REPEAT), then press ENTER. The options for “REPEAT” appear. 3 Press X/x to select the item to be repeated. ◆ When playing a DVD VIDEO • DISC: repeats all of the titles. • TITLE: repeats the current title on a disc. • CHAPTER: repeats the current chapter. ◆ When playing a DVD-VR mode disc • DISC: repeats all the titles of the selected type. • TITLE: repeats the current title on a disc. • CHAPTER: repeats the current chapter. ◆ When playing a VIDEO CD or CD • DISC: repeats all of the tracks. • TRACK: repeats the current track. ◆ When playing a DATA CD or DATA DVD • DISC: repeats all of the albums. • ALBUM: repeats the current album. • TRACK (MP3 audio tracks only): repeats the current track. ◆ When Programme Play or Shuffle Play is activated • ON: repeats Programme Play or Shuffle Play. 4 Press ENTER. Repeat Play starts. To return to normal play Press CLEAR, or select “OFF” in step 3. z Hint You can set Repeat Play while the player is stopped. After selecting the “REPEAT” option, press H. Repeat Play starts. Notes • You cannot use this function with VIDEO CDs and Super VCDs with PBC playback. • When repeating a DATA CD/DATA DVD which contains MP3 audio tracks and JPEG image files, and their playing times are not the same, the sound will not match the image. • When “MODE (MP3, JPEG)” is set to “IMAGE (JPEG)” (page 49), you cannot select “TRACK.” DISC TITLE CHAPTER OFF 1 8 ( 3 4 ) 1 2 ( 2 7 ) T 1 : 3 2 : 5 5 DVD VIDEO OFF ,continued 30 Repeating a specific portion (A-B Repeat Play) You can play a specific portion of a title, chapter or track repeatedly. (This function is useful when you want to memorize lyrics, etc.) 1 Press DISPLAY during playback. The Control Menu appears. 2 Press X/x to select (A-B REPEAT), then press ENTER. The options for “A-B REPEAT” appear. 3 Press X/x to select “SET t,” then press ENTER. The “A-B REPEAT” setting bar appears. 4 During playback, when you find the starting point (point A) of the portion to be played repeatedly, press ENTER. The starting point (point A) is set. 5 When you reach the ending point (point B), press ENTER again. The set points are displayed and the player starts repeating this specific portion. To return to normal play Press CLEAR, or select “OFF” in step 3. Notes • When you set A-B Repeat Play, the settings for Shuffle Play, Repeat Play, and Programme Play are cancelled. • A-B Repeat Play does not work across multiple titles. • You may not set A-B Repeat Play for contents on a DVD-RW/DVD-R (VR mode) that contains still pictures. PLAY SET OFF OFF 1 8 ( 3 4 ) 1 2 ( 2 7 ) T 1 : 3 2 : 5 5 DVD VIDEO A 18 - 1:32:30 B A 18 - 1:32:55 B 18 - 1:33:05 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 1-8 DVP-NS15/NS51P/NS43P/NS53P/K56P 31 Searching for a Scene Searching for a Scene Searching for a Particular Point on a Disc (Scan, Slow-motion Play, Freeze Frame) You can quickly locate a particular point on a disc by monitoring the picture or playing back slowly. Notes • Depending on the disc, you may not be able to do some of the operations described. • For DATA CDs/DATA DVDs, you can search for a particular point only on an MP3 audio track. Locating a point quickly by playing a disc in fast forward or fast reverse (Scan) Press m or M while playing a disc. When you find the point you want, press H to return to normal speed. Each time you press m or M during scan, the scan speed changes. With each press the indication changes as shown below. Actual speeds may differ between discs. Playback direction Opposite direction The “× 2B”/ “× 2b” playback speed is about twice the normal speed. The “3M”/“3m” playback speed is faster than “2M”/“2m” and the “2M”/“2m” playback speed is faster than “1M”/ “1m.” Watching frame by frame (Slow-motion Play) Press m or M when the player is in pause mode. To return to normal speed, press H. Each time you press m or M during Slow-motion Play, the playback speed changes. Two speeds are available. With each press the indication changes as follows: Playback direction 2 y 1 Opposite direction (DVD/DVD-VR mode only) 2 y 1 The “2 y”/“2 ” playback speed is slower than “1 y”/“1 .” Playing one frame at a time (Freeze Frame) When the player is in the pause mode, press STEP to go to the next frame. Press STEP to go to the preceding frame (DVD/DVD-VR mode only). To return to normal playback, press H. Note You cannot search for a still picture on a DVD-RW/ DVD-R in VR mode. STEP STEP × 2B t 1M t 2M t 3M 3M (DVD VIDEO/DVD-VR mode/ VIDEO CD only) × 2B (DVD VIDEO/CD only) × 2b t 1m t 2m t 3m 3m (DVD VIDEO/DVD-VR mode/ VIDEO CD only) × 2b (DVD VIDEO only) 32 Searching for a Title/ Chapter/Track/Scene, etc. You can search a DVD by title or chapter, and you can search a VIDEO CD/CD/DATA CD/ DATA DVD by track, index, file, or scene. As titles and tracks are assigned unique numbers on the disc, you can select the desired one by entering its number. You can also search for a scene using the time code. 1 Press DISPLAY (When playing a DATA CD or DATA DVD with JPEG image files, press twice). The Control Menu appears. 2 Press X/x to select the search method. ◆ When playing a DVD VIDEO/DVD-VR mode disc TITLE CHAPTER TIME/TEXT Select “TIME/TEXT” to search for a starting point by inputting the time code. ◆ When playing a VIDEO CD or Super VCD without PBC playback TRACK INDEX ◆ When playing a VIDEO CD or Super VCD with PBC playback SCENE ◆ When playing a CD TRACK ◆ When playing a DATA CD/DATA DVD ALBUM TRACK (MP3 audio tracks only) FILE (JPEG image files only) Example: when you select CHAPTER “** (**)” is selected (** refers to a number). The number in parentheses indicates the total number of titles, chapters, tracks, indexes, scenes, album or files. 3 Press ENTER. “** (**)” changes to “-- (**).” 4 Press the number buttons to select the title, chapter, track, index, scene, etc., number you want to search. If you make a mistake Cancel the number by pressing CLEAR, then select another number. ENTER DISPLAY CLEAR Number buttons PLAY 1 8 ( 3 4 ) 1 2 ( 2 7 ) DVD VIDEO T 1 : 3 2 : 5 5 Selected row PLAY DVD VIDEO 1 2 ( 2 7 ) T 1 : 3 2 : 5 5 ( 3 4 ) 33 Searching for a Scene 5 Press ENTER. The player starts playback from the selected number. To search for a scene using the time code (DVD VIDEO/DVD-VR mode only) 1 In step 2, select TIME/TEXT. “T **:**:**” (playing time of the current title) is selected. 2 Press ENTER. “T **:**:**” changes to “T --:--:--.” 3 Input the time code using the number buttons, then press ENTER. For example, to find the scene at 2 hours, 10 minutes, and 20 seconds after the beginning, just enter “2:10:20.” z Hints • When the Control Menu display is turned off, you can search for a chapter (DVD VIDEO/DVD-VR mode), track (CD/DATA CD/DATA DVD) by pressing the number buttons and ENTER. • You can display the first scene of titles, chapters, or tracks recorded on the disc on a screen divided into 9 sections. You can start playback directly by selecting one of the scenes. For details, see “Searching by Scene (PICTURE NAVIGATION)” (page 33). Notes • The title, chapter, or track number displayed is the same number recorded on the disc. • You cannot search for a scene on a DVD+RW/ DVD+R using the time code. Searching by Scene (PICTURE NAVIGATION) You can divide the screen into 9 subscreens and find the desired scene quickly. 1 Press PICTURE NAVI during playback. The following display appears. 2 Press PICTURE NAVI repeatedly to select an item. • CHAPTER VIEWER (DVD VIDEO only): displays the first scene of each chapter. • TITLE VIEWER (DVD VIDEO only): displays the first scene of each title. • TRACK VIEWER (VIDEO CD/ Super VCD only): displays the first scene of each track. DISPLAY PICTURE NAVI RETURN ENTER CHAPTER VIEWER ENTER ,continued 34 3 Press ENTER. The first scene of each chapter, title, or track appears as follows. 4 Press C/X/x/c to select a chapter, title, or track, and press ENTER. Playback starts from the selected scene. To return to normal play during setting Press O RETURN or DISPLAY. z Hint If there are more than 9 chapters, titles, or tracks, V is displayed at the bottom right of the screen. To display the additional chapters, titles, or tracks, select the bottom scenes and press x. To return to the previous scene, select the top scenes and press X. Note Depending on the disc, you may not be able to select some items. 1 4 7 2 5 8 3 6 9 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 1-9 DVP-NS15/NS51P/NS43P/NS53P/K56P 35 Viewing Information About the Disc Viewing Information About the Disc Checking the Playing Time and Remaining Time You can check the playing time and remaining time of the current title, chapter, or track. Also, you can check the DVD/CD text or track name (MP3 audio), recorded on the disc. 1 Press TIME/TEXT during playback. The following display appears. 2 Press TIME/TEXT repeatedly to change the time information. The available time information depends upon the type of disc you are playing. ◆ When playing a DVD VIDEO or DVD-VR mode disc • T *:*:* (hours: minutes: seconds) Playing time of the current title • T–*:*:* Remaining time of the current title • C *:*:* Playing time of the current chapter • C–*:*:* Remaining time of the current chapter ◆ When playing a VIDEO CD or Super VCD (with PBC functions) • *:* (minutes: seconds) Playing time of the current scene ◆ When playing a VIDEO CD (without PBC functions), or CD • T *:* (minutes: seconds) Playing time of the current track • T–*:* Remaining time of the current track • D *:* Playing time of the current disc • D–*:* Remaining time of the current disc ◆ When playing a Super VCD (without PBC functions) • T *:* (minutes: seconds) Playing time of the current track ◆ When playing a DATA CD (MP3 audio)/ DATA DVD (MP3 audio) • T *:* (minutes: seconds) Playing time of the current track TIME/TEXT T 1:01:57 Time information ,continued 36 Checking the play information of the disc To check the DVD/CD text Press TIME/TEXT repeatedly in step 2 to display text recorded on the DVD/CD. The DVD/CD text appears only when text is recorded in the disc. You cannot change the text. If the disc does not contain text, “NO TEXT” appears. To check DATA CD (MP3 audio)/DATA DVD (MP3 audio) album name, etc. By pressing TIME/TEXT while playing MP3 audio tracks on a DATA CD/DATA DVD, you can display the name of the album/track, and the audio bit rate (the amount of data per second of the current audio track) on your TV screen. Checking the information on the front panel display You can view the time information and text displayed on the TV screen also on the front panel display. The information on the front panel display changes as follows when you change the time information on your TV screen. When playing a DVD VIDEO or DVD-VR mode disc BRAHMS SYMPHONY T 17:30 128k JAZZ RIVER SIDE Bit rate Album name Track name Playing time of the current title Remaining time of the current title Playing time of the current chapter Remaining time of the current chapter Text Current title and chapter number (returns to top automatically) 37 Viewing Information About the Disc When playing a DATA CD (MP3 audio)/ DATA DVD (MP3 audio) When playing a VIDEO CD (without PBC functions), or CD z Hints • When playing VIDEO CDs without PBC functions, the track number and the index number are displayed after text. • When playing VIDEO CDs with PBC functions, the scene number or the playing time are displayed. • Long text that does not fit in a single line will scroll across the front panel display. • You can also check the time information and text using the Control Menu (page 11). Notes • Depending on the type of disc being played, the DVD/CD text or track name may not be displayed. • The player can only display the first level of the DVD/CD text, such as the disc name or title. • Playing time of MP3 audio tracks may not be displayed correctly. • If you play a disc containing JPEG image files only, “NO AUDIO DATA” appears when “MODE (MP3, JPEG)” is set to “AUTO,” “JPEG” appears when “MODE (MP3, JPEG)” is set to “IMAGE (JPEG)” in the front panel display. Playing time and number of the current track Track name Current album and track number (returns to top automatically) Playing time and number of the current track Remaining time of the current track Remaining time of the disc Text Playing time of the disc 38 Sound Adjustments Changing the Sound When playing a DVD VIDEO recorded in multiple audio formats (PCM, Dolby Digital, MPEG audio, or DTS), you can change the audio format. If the DVD VIDEO is recorded with multilingual tracks, you can also change the language. With CDs, DATA CDs/DATA DVDs, or VIDEO CDs, you can select the sound from either the right or left channel and listen to the sound of the selected channel through both the right and left speakers. For example, when playing a disc containing a song with the vocals on the right channel and the instruments on the left channel, you can hear the instruments from both speakers by selecting the left channel. 1 Press /AUDIO during playback. The following display appears. 2 Press /AUDIO repeatedly to select the desired audio signal. ◆ When playing a DVD VIDEO Depending on the DVD VIDEO, the choice of language varies. When 4 digits are displayed, they indicate a language code. See “Language Code List” on page 68 to see which language the code represents. When the same language is displayed two or more times, the DVD VIDEO is recorded in multiple audio formats. ◆ When playing a DVD-VR mode disc The types of sound tracks recorded on a disc are displayed. The default setting is underlined. Example: • 1: MAIN (main sound) • 1: SUB (sub sound) • 1: MAIN+SUB (main and sub sound) ◆ When playing a VIDEO CD, CD, or DATA CD (MP3 audio)/DATA DVD (MP3 audio) The default setting is underlined. • STEREO: the standard stereo sound • 1/L: the sound of the left channel (monaural) • 2/R: the sound of the right channel (monaural) ◆ When playing a Super VCD The default setting is underlined. • 1:STEREO: the stereo sound of the audio track 1 • 1:1/L: the sound of the left channel of the audio track 1 (monaural) • 1:2/R: the sound of the right channel of the audio track 1 (monaural) • 2:STEREO: the stereo sound of the audio track 2 • 2:1/L: the sound of the left channel of the audio track 2 (monaural) • 2:2/R: the sound of the right channel of the audio track 2 (monaural) Notes • While playing a Super VCD on which the audio track 2 is not recorded, no sound will come out when you select “2:STEREO,” “2:1/L,” or “2:2/R.” • When playing DVD-RW/DVD-R in VR mode: If you connect to an AV amplifier (receiver) using the DIGITAL OUT (COAXIAL or OPTICAL) jack and want to switch between the sound tracks, set “DOLBY DIGITAL” to “D-PCM” in “AUDIO SETUP.” /AUDIO 1:ENGLISH DOLBY DIGITAL 3/2.1 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 1-10 DVP-NS15/NS51P/NS43P/NS53P/K56P 39 Sound Adjustments Checking the audio signal format You can check the audio signal format by pressing /AUDIO repeatedly during playback. The format of the current audio signal (Dolby Digital, DTS, PCM, etc.) appears as shown below. Example: Dolby Digital 5.1 ch Example: Dolby Digital 3 ch About audio signals Audio signals recorded in a disc contain the sound elements (channels) shown below. Each channel is output from a separate speaker. • Front (L) • Front (R) • Centre • Rear (L) • Rear (R) • Rear (Monaural): This signal can be either the Dolby Surround Sound processed signals or the Dolby Digital sound’s monaural rear audio signals. • LFE (Low Frequency Effect) signal Notes • If “DTS” is set to “OFF” in “AUDIO SETUP” (page 61) the DTS track selection option will not appear on the screen even if the disc contains DTS tracks. • MPEG audio signals with more than two channels will appear as shown above (3/2.1, 2/1), but only the Front (L) and Front (R) signals will be output from your two front speakers. TV Virtual Surround Settings (TVS) When you connect a stereo TV or 2 front speakers, TVS (TV Virtual Surround) lets you enjoy surround sound effects by using sound imaging to create virtual rear speakers from the sound of the front speakers (L: left, R: right) without using actual rear speakers. TVS was developed by Sony to produce surround sound for home use using just a stereo TV. This only works when playing a multichannel Dolby audio soundtrack. Furthermore, if the player is set up to output the signal from the DIGITAL OUT (OPTICAL or COAXIAL) jack, the surround effect will only be heard when “DOLBY DIGITAL” is set to “D- PCM” and “MPEG” is set to “PCM” in “AUDIO SETUP” (page 61). 1 Press SUR during playback. The following display appears. 2 Press SUR repeatedly to select one of the TVS sounds. See the explanations given for each item in the following section. • TVS DYNAMIC THEATER • TVS DYNAMIC • TVS WIDE • TVS NIGHT • TVS STANDARD 1:ENGLISH DOLBY DIGITAL 3 / 2 .1 Rear (L/R) Front (L/R) + Centre LFE (Low Frequency Effect) 2:SPANISH DOLBY DIGITAL 2 / 1 Front (L/R) Rear (Monaural) SUR TVS DYNAMIC THEATER ,continued 40 To cancel the setting Select “OFF” in step 2. ◆TVS DYNAMIC THEATER Creates one set of LARGE virtual rear speakers and virtual subwoofer from the sound of the front speakers (L, R) without using actual rear speakers and subwoofer (shown below). This mode is effective when the distance between the front L and R speakers is short, such as with built-in speakers on a stereo TV. ◆TVS DYNAMIC Creates one set of virtual rear speakers from the sound of the front speakers (L, R) without using actual rear speakers (shown below). This mode is effective when the distance between the front L and R speakers is short, such as with built-in speakers on a stereo TV. ◆TVS WIDE Creates five sets of virtual rear speakers from the sound of the front speakers (L, R) without using actual rear speakers (shown below). This mode is effective when the distance between the front L and R speakers is short, such as with built-in speakers on a stereo TV. ◆TVS NIGHT Large sounds, such as explosions, are suppressed, but the quieter sounds are unaffected. This feature is useful when you want to hear the dialogue and enjoy the surround sound effects of “TVS WIDE” at low volume. ◆TVS STANDARD Creates three sets of virtual rear speakers from the sound of the front speakers (L, R) without using actual rear speakers (shown below). Use this setting when you want to use TVS with 2 separate speakers. Notes • When the playing signal does not contain a signal for the rear speakers, the surround effects cannot be heard. • When you select one of the TVS modes, turn off the surround setting of the connected TV or amplifier (receiver). • Make sure that your listening position is between and at an equal distance from your speakers, and that the speakers are located in similar surroundings. • Not all discs will respond to the “TVS NIGHT” function in the same way. • The TVS effects do not work when using the Fast Play or Slow Play functions, even though you can change the TVS modes. TV Sub woofer TV TV L: Front speaker (left) R: Front speaker (right) : Virtual speaker L R 41 Enjoying Movies Enjoying Movies Changing the Angles If various angles (multi-angles) for a scene are recorded on the DVD VIDEO, “ ” appears in the front panel display. This means that you can change the viewing angle. 1 Press /ANGLE during playback. The number of the angle appears on the display. 2 Press /ANGLE repeatedly to select an angle number. The scene changes to the selected angle. Note Depending on the DVD VIDEO, you may not be able to change the angles even if multi-angles are recorded on the DVD VIDEO. Displaying the Subtitles If subtitles are recorded on the discs, you can change the subtitles or turn them on and off whenever you want while playing a DVD. 1 Press /SUBTITLE during playback. The following display appears. 2 Press /SUBTITLE repeatedly to select a setting. ◆ When playing a DVD VIDEO Select the language. Depending on the DVD VIDEO, the choice of language varies. When 4 digits are displayed, they indicate a language code. See “Language Code List” on page 68 to see which language the code represents. ◆ When playing a DVD-VR mode disc Select “ON.” To turn off the subtitles Select “OFF” in step 2. /ANGLE 2 /SUBTITLE 1:ENGLISH ,continued 42 Notes • Depending on the DVD VIDEO, you may not be able to change the subtitles even if multilingual subtitles are recorded on it. You also may not be able to turn them off. • While playing a disc with subtitles, the subtitle may disappear when you press FAST PLAY or SLOW PLAY button. Adjusting the Playback Picture (CUSTOM PICTURE MODE) You can adjust the video signal of the DVD, VIDEO CD or DATA CD/DATA DVD in JPEG format, from the player to obtain the picture quality you want. Choose the setting that best suits the programme you are watching. When you select “MEMORY,” you can make further adjustments to each element of the picture (colour, brightness, etc.). 1 Press DISPLAY during playback (When playing a DATA CD or DATA DVD with JPEG image files, press twice). The Control Menu appears. 2 Press X/x to select (CUSTOM PICTURE MODE), then press ENTER. The options for “CUSTOM PICTURE MODE” appear. DISPLAY RETURN ENTER DVD VIDEO 1 8 ( 3 4 ) 1 2 ( 2 7 ) T 1 : 3 2 : 5 5 DYNAMIC 1 STANDARD STANDARD www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 1-11 DVP-NS15/NS51P/NS43P/NS53P/K56P 43 Enjoying Movies 3 Press X/x to select the setting you want. The default setting is underlined. • STANDARD: displays a standard picture. • DYNAMIC 1: produces a bold dynamic picture by increasing the picture contrast and the colour intensity. • DYNAMIC 2: produces a more dynamic picture than DYNAMIC 1 by further increasing the picture contrast and colour intensity. • CINEMA 1: enhances details in dark areas by increasing the black level. • CINEMA 2: white colours become brighter and black colours become richer, and the colour contrast is increased. • MEMORY: adjusts the picture in greater detail. 4 Press ENTER. The selected setting takes effect. z Hint When you watch a movie, “CINEMA 1” or “CINEMA 2” is recommended. Adjusting the picture items in “MEMORY” You can adjust each element of the picture individually. • PICTURE: changes the contrast • BRIGHTNESS: changes the overall brightness • COLOR: makes the colours deeper or lighter • HUE: changes the colour balance 1 In step 3 of “Adjusting the Playback Picture,” select “MEMORY” and press ENTER. The “PICTURE” adjustment bar appears. 2 Press C/c to adjust the picture contrast. To go to the next or previous picture item without saving the current setting, press X/x. 3 Press ENTER. The adjustment is saved, and “BRIGHTNESS” adjustment bar appears. 4 Repeat step 2 and 3 to adjust “BRIGHTNESS,” “COLOR,” and “HUE.” To turn off the display Press O RETURN , or DISPLAY. PICTURE 0 44 Sharpening the Picture (SHARPNESS) You can enhance the outlines of images to produce a sharper picture. 1 Press DISPLAY during playback (When playing a DATA CD or DATA DVD with JPEG image files, press twice). The Control Menu appears. 2 Press X/x to select (SHARPNESS), then press ENTER. The options for “SHARPNESS” appear. 3 Press X/x to select a level. • 1: enhances the outline. • 2: enhances the outline more than 1. 4 Press ENTER. The selected setting takes effect. To cancel the “SHARPNESS” setting Select “OFF” in step 3. ENTER DISPLAY DVD VIDEO 1 8 ( 3 4 ) 1 2 ( 2 7 ) T 1 : 3 2 : 5 5 2 1 OFF OFF 45 Enjoying MP3 Audio and JPEG Images Enjoying MP3 Audio and JPEG Images About MP3 Audio Tracks and JPEG Image Files MP3 is audio compression technology that satisfies the ISO/IEC MPEG regulations. JPEG is image compression technology. You can play DATA CDs/DATA DVDs that contain MP3 audio tracks or JPEG image files. DATA CDs/DATA DVDs that the player can play You can play back DATA CDs (CD-ROMs/ CD-Rs/CD-RWs) or DATA DVDs (DVD- ROMs/DVD+RWs/DVD+Rs/DVD-RWs/ DVD-Rs) recorded in MP3 (MPEG-1 Audio Layer III) and JPEG format. However, this player only plays DATA CDs whose logical format is ISO 9660 Level 1/ Level 2 or Joliet, and DATA DVDs of Universal Disk Format (UDF). Refer to the instructions supplied with the disc drives and the recording software (not supplied) for details on the recording format. Note The player may not be able to play some DATA CDs/DATA DVDs created in the Packet Write format. MP3 audio track or JPEG image file that the player can play The player can play the following tracks and files: – MP3 audio tracks with the extension “.MP3.” – JPEG image files with the extension “.JPEG” or “.JPG.” – JPEG image files that conform to the DCF* image file format. * “Design rule for Camera File system”: Image standards for digital cameras regulated by JEITA (Japan Electronics and Information Technology Industries Association). Notes • The player will play any data with the extension “.MP3,” “.JPG,” or “.JPEG,” even if they are not in MP3 or JPEG format. Playing these data may generate a loud noise which could damage your speaker system. • The player does not conform to audio tracks in mp3PRO format. • Some JPEG files cannot be played. About playback order of albums, tracks, and files Albums play in the following order: ◆Structure of disc contents ROOT Tree 1 Tree 2 Tree 3 Tree 4 Tree 5 Album Track or file ,continued 46 When you insert a DATA CD/DATA DVD and press H, the numbered tracks (or files) are played sequentially, from 1 through 7. Any sub-albums/tracks (or files) contained within a currently selected album take priority over the next album in the same tree. (Example: C contains D so 4 is played before 5.) When you press MENU and the list of album names appears (page 47), the album names are arranged in the following order: A t B t C t D t F t G. Albums that do not contain tracks (or files) (such as album E) do not appear in the list. z Hints • If you add numbers (01, 02, 03, etc.) to the front of the track/file names when you store the tracks (or files) in a disc, the tracks and files will be played in that order. • Since a disc with many trees takes longer to start playback, it is recommended that you create albums with no more than two trees. Notes • Depending on the software you use to create the DATA CD/DATA DVD, the playback order may differ from the above illustration. • The playback order above may not be applicable if there are more than 200 albums and 300 tracks/ files in each album. • The player can recognize up to 200 albums (the player will count just albums, including albums that do not contain MP3 audio tracks and JPEG image files). The player will not play any albums beyond the 200th album. • Proceeding to the next or another album may take some time. Playing MP3 Audio Tracks or JPEG Image Files You can play MP3 audio tracks and JPEG image files on DATA CDs (CD-ROMs/CD- Rs/CD-RWs) or DATA DVDs (DVD-ROMs/ DVD+RWs/DVD+Rs/DVD-RWs/DVD-Rs). z Hint You can view the disc information while playing MP3 audio tracks (page 35). Notes • DATA CDs recorded in KODAK Picture CD format automatically start playing when inserted. • If no MP3 audio track or JPEG image file is recorded on the DATA CD/DATA DVD, “No audio data” or “No image data” appears on the screen. PICTURE NAVI RETURN ENTER CLEAR ZOOM MENU www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 1-12 DVP-NS15/NS51P/NS43P/NS53P/K56P 47 Enjoying MP3 Audio and JPEG Images Selecting an album 1 Press MENU. The list of albums on the disc appears. When an album is being played, its title is shaded. 2 Press X/x to select the album you want to play. 3 Press H. Playback starts from the selected album. To select MP3 audio tracks, see “Selecting an MP3 audio track” (page 47). To select JPEG image files, see “Selecting a JPEG image file” (page 48). To stop playback Press x. To go to the next or previous page Press c or C. To turn on or off the display Press MENU repeatedly. z Hint Of the selected album, you can select to play only the MP3 audio tracks, JPEG image files, or both, by setting “MODE (MP3, JPEG)” (page 49). Selecting an MP3 audio track 1 After step 2 of “Selecting an album,” press ENTER. The list of tracks in the album appears. 2 Press X/x to select a track, and press ENTER. Playback starts from the selected track. To stop playback Press x. To go to the next or previous page Press c or C. To return to the previous display Press O RETURN. To go to the next or previous MP3 audio track Press > or . during playback. You can select the first track of the next album by pressing > during playback of the last track of the current album. Note that you cannot return to the previous album by using ., and that you need to select the previous album from the album list. 1 ( 3 0 ) R O C K B E S T H I T K A R A O K E J A Z Z R & B M Y F A V O R I T E S O N G S C L A S S I C A L S A L S A O F C U B A B O S S A N O V A J A Z Z 1 ( 9 0 ) 0 1 S H E I S S P E C I A L 0 2 A L L Y O U N E E D I S . . . 0 3 S P I C Y L I F E 0 4 H A P P Y H O U R 0 5 R I V E R S I D E 0 6 5 0 7 T A K E T I M E , T A K E T I M E ,continued 48 Selecting a JPEG image file 1 After step 2 of “Selecting an album,” press PICTURE NAVI. The image files in the album appear in 16 subscreens. A scroll box is displayed on the right. To display the additional image, select the bottom images and press x. To return to the previous image, select the top images and press X. 2 Press C/X/x/c to select the image you want to view, and press ENTER. The selected image appears. Example To go to the next or previous JPEG image file Press C or c during playback. You can select the first file of the next album by pressing c during playback of the last file of the current album. Note that you cannot return to the previous album by using C, and that you need to select the previous album from the album list. To rotate a JPEG image Press X/x while viewing the image. Each time you press X, the image rotates counterclockwise by 90 degrees. To return to normal view, press CLEAR. Note that the view also returns to normal if you press C/c to go to the next or previous image. Example: when X is pressed once. To magnify a JPEG image (ZOOM) Press ZOOM while viewing the image. You can enlarge the image up to four times the original size, and scroll using C/X/x/c. To return to normal view, press CLEAR. ◆When pressed once (x2) The image enlarges twice the original size. ◆When pressed twice (x4) The image enlarges four times the original size. To stop viewing the JPEG image Press x. z Hints • While viewing JPEG image files, you can set options such as “INTERVAL” (page 50), “EFFECT” (page 50), and “SHARPNESS” (page 44). • You can view JPEG images files without MP3 audio by setting “MODE (MP3, JPEG)” to “IMAGE (JPEG)” (page 49). • The date the picture was taken is displayed beside “DATE” in the Control Menu (page 11). Note that no date may appear depending on the digital camera. Note PICTURE NAVI does not work if “AUDIO (MP3)” is selected in “MODE (MP3, JPEG)” (page 49). 1 2 3 4 5 6 7 8 13 14 15 16 9 10 11 12 Rotating direction 49 Enjoying MP3 Audio and JPEG Images Enjoying JPEG Images as a Slide Show You can play JPEG image files on a DATA CD/DATA DVD successively as a slide show. 1 Press MENU. The list of albums on the DATA CD/ DATA DVD appears. 2 Press X/x to select an album. 3 Press H. The JPEG images in the selected album start playing as a slide show. To stop playback Press x. Notes • The slide show stops when X/x or ZOOM is pressed.To resume the slide show, press H. • This function does not work if “MODE (MP3, JPEG)” is set to “AUDIO (MP3)” (page 49). Viewing a slide show with sound (MODE (MP3, JPEG)) When JPEG image files and MP3 audio tracks are placed in the same album, you can enjoy a slide show with sound. 1 Press DISPLAY during stop mode. The Control Menu appears. 2 Press X/x to select (MODE (MP3, JPEG)), and press ENTER. The options for “MODE (MP3, JPEG)” appear. 3 Press X/x to select “AUTO” (default), and press ENTER. • AUTO: plays both the JPEG image files and MP3 audio tracks in the same album as a slide show. • AUDIO (MP3): plays only MP3 audio tracks continuously. • IMAGE (JPEG): plays only JPEG image files continuously. 4 Press MENU. The list of albums on the DATA CD/ DATA DVD appears. 5 Press X/x to select the album that contains both the MP3 audio tracks and JPEG images you want to play. 6 Press H. A slide show starts with sound. MENU DISPLAY ENTER 1 ( 3 0 ) R O C K B E S T H I T K A R A O K E J A Z Z R & B M Y F A V O R I T E S O N G S C L A S S I C A L S A L S A O F C U B A B O S S A N O V A DATA CD MP3 1 8 ( 3 4 ) 1 2 ( 2 7 ) T 3 2 : 5 5 IMAGE (JPEG) AUDIO (MP3) AUTO AUTO 1 ( 3 0 ) R O C K B E S T H I T K A R A O K E J A Z Z R & B M Y F A V O R I T E S O N G S C L A S S I C A L S A L S A O F C U B A B O S S A N O V A ,continued 50 z Hints • To repeat both MP3 audio tracks and JPEG image files in a single album, repeat the same MP3 audio track or album when “MODE (MP3, JPEG)” is set to “AUTO.” See “Playing repeatedly (Repeat Play)” (page 29) to repeat the track or album. • The player recognizes a maximum of 200 albums regardless of the selected mode. Of each album, the player recognizes up to 300 MP3 audio tracks and 300 JPEG image files when “AUTO” is selected, 600 MP3 audio tracks when “AUDIO (MP3)” is selected, 600 JPEG image files when “IMAGE (JPEG)” is selected. Notes • This function does not work if the MP3 audio tracks and JPEG image files are not placed in the same album. • If playing time of JPEG image or MP3 audio is longer than the other, the longer one continues without sound or image. • If you play large MP3 track data and JPEG image data at the same time, the sound may skip. It is recommended that you set the MP3 bit rate to 128 kbps or lower when creating the file. If the sound still skips, then reduce the size of the JPEG file. Setting the pace for a slide show (INTERVAL) You can set the time the slides are displayed on the screen. 1 Press DISPLAY twice while viewing a JPEG image or when the player is in stop mode. The Control Menu appears. 2 Press X/x to select (INTERVAL), then press ENTER. The options for “INTERVAL” appear. 3 Press X/x to select a setting. The default setting is underlined. • NORMAL: sets the duration to between 6 to 9 seconds. • FAST: sets a duration shorter than NORMAL. • SLOW 1: sets a duration longer than NORMAL. • SLOW 2: sets a duration longer than SLOW 1. 4 Press ENTER. Note Some JPEG files, especially progressive JPEG files or JPEG files of 3,000,000 pixels or more, may take longer to display than others, which may make the duration seem longer than the setting you selected. Selecting the slides’ appearance (EFFECT) You can select the way the slides are displayed during a slide show. 1 Press DISPLAY twice while viewing a JPEG image or when the player is in stop mode. 2 Press X/x to select (EFFECT), then press ENTER. The options for “EFFECT” appear. 3 Press X/x to select a setting. The default setting is underlined. • MODE 1: the image sweeps in from top to bottom. • MODE 2: the image sweeps in from left to right. • MODE 3: the image stretches out from the centre of the screen. • MODE 4: the images randomly cycle through the effects. • MODE 5: the next image slides over the previous image. • OFF: turns off this function. 4 Press ENTER. 2 9 / 1 0 / 2 0 0 6 1( NORMAL DATA CD JPEG NORMAL FAST SLOW 1 SLOW 2 4) 3 ( 12) 2 9 / 1 0 / 2 0 0 6 1( MODE 1 DATA CD JPEG MODE 1 MODE 2 MODE 3 MODE 4 MODE 5 OFF 4) 3 ( 1 2) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 1-13 DVP-NS15/NS51P/NS43P/NS53P/K56P 51 Using Various Additional Functions Using Various Additional Functions Locking Discs (CUSTOM PARENTAL CONTROL, PARENTAL CONTROL) You can set two kinds of playback restrictions for a disc. • Custom Parental Control You can set playback restrictions so that the player will not play inappropriate discs. • Parental Control Playback of some DVD VIDEOs can be limited according to a predetermined level such as the age of the users. Scenes may be blocked or replaced with different scenes. The same password is used for both Parental Control and Custom Parental Control. Custom Parental Control You can set the same Custom Parental Control password for up to 40 discs. When you set the 41st-disc, the first disc is cancelled. 1 Insert the disc you want to lock. If the disc is playing, press x to stop playback. 2 Press DISPLAY while the player is in stop mode. The Control Menu appears. 3 Press X/x to select (PARENTAL CONTROL), then press ENTER. The options for “PARENTAL CONTROL” appear. 4 Press X/x to select “ON t,” then press ENTER. ◆ If you have not entered a password The display for registering a new password appears. Enter a 4-digit password using the number buttons, then press ENTER. The display for confirming the password appears. ◆ When you have already registered a password The display for entering the password appears. 5 Enter or re-enter your 4-digit password using the number buttons, then press ENTER. “Custom parental control is set.” appears and then the screen returns to the Control Menu. To turn off the Custom Parental Control function 1 Follow steps 1 to 3 of “Custom Parental Control.” 2 Press X/x to select “OFF t,” then press ENTER. 3 Enter your 4-digit password using the number buttons, then press ENTER. ENTER DISPLAY Number buttons STOP 1 8 ( 3 4 ) 1 2 ( 2 7 ) T 1 : 3 2 : 5 5 DVD VIDEO PASSWORD ON PLAYER OFF PARENTAL CONTROL Enter a new 4-digit password, then press . ENTER ,continued 52 To play a disc for which Custom Parental Control is set 1 Insert the disc for which Custom Parental Control is set. The “CUSTOM PARENTAL CONTROL” display appears. 2 Enter your 4-digit password using the number buttons, then press ENTER. The player is ready for playback. z Hint If you forget your password, enter the 6-digit number “199703” using the number buttons when the “CUSTOM PARENTAL CONTROL” display asks you for your password, then press ENTER. The display will ask you to enter a new 4-digit password. Parental Control (limited playback) Playback of some DVD VIDEOs can be limited according to a predetermined level such as the age of the users. The “PARENTAL CONTROL” function allows you to set a playback limitation level. 1 Press DISPLAY while the player is in stop mode. The Control Menu appears. 2 Press X/x to select (PARENTAL CONTROL), then press ENTER. The options for “PARENTAL CONTROL” appear. 3 Press X/x to select “PLAYER t,” then press ENTER. ◆ If you have not entered a password The display for registering a new password appears. Enter a 4-digit password using the number buttons, then press ENTER. The display for confirming the password appears. ◆ When you have already registered a password The display for entering the password appears. 4 Enter or re-enter your 4-digit password using the number buttons, then press ENTER. The display for setting the playback limitation level appears. 5 Press X/x to select “STANDARD,” then press ENTER. The selection items for “STANDARD” are displayed. 6 Press X/x to select a geographic area as the playback limitation level, then press ENTER. CUSTOM PARENTAL CONTROL Custom parental control is already set. To play, enter your password and press . ENTER STOP 1 8 ( 3 4 ) 1 2 ( 2 7 ) T 1 : 3 2 : 5 5 DVD VIDEO PASSWORD ON PLAYER OFF PARENTAL CONTROL Enter a new 4-digit password, then press . ENTER PARENTAL CONTROL LEVEL: OFF USA STANDARD: PARENTAL CONTROL LEVEL: OFF USA STANDARD: USA OTHERS 53 Using Various Additional Functions The area is selected. When you select “OTHERS t,” select and enter a standard code in the table on page 68 using the number buttons. 7 Press X/x to select “LEVEL,” then press ENTER. The selection items for “LEVEL” are displayed. 8 Select the level you want using X/x, then press ENTER. Parental Control setting is complete. The lower the value, the stricter the limitation. To turn off the Parental Control function Set “LEVEL” to “OFF” in step 8. To play a disc for which Parental Control is set 1 Insert the disc and press H. The display for entering your password appears. 2 Enter your 4-digit password using the number buttons, then press ENTER. The player starts playback. z Hint If you forget your password, remove the disc and repeat steps 1 to 3 of “Parental Control (limited playback).” When you are asked to enter your password, enter “199703” using the number buttons, then press ENTER. The display will ask you to enter a new 4-digit password. After you enter a new 4-digit password, replace the disc in the player and press H. When the display for entering your password appears, enter your new password. Notes • When you play discs which do not have the Parental Control function, playback cannot be limited on this player. • Depending on the disc, you may be asked to change the parental control level while playing the disc. In this case, enter your password, then change the level. If the Resume Play mode is cancelled, the level returns to the previous level. Changing the password 1 Press DISPLAY while the player is in stop mode. The Control Menu appears. 2 Press X/x to select (PARENTAL CONTROL), then press ENTER. The options for “PARENTAL CONTROL” appear. 3 Press X/x to select “PASSWORD t,” then press ENTER. The display for entering the password appears. 4 Enter your 4-digit password using the number buttons, then press ENTER. 5 Enter a new 4-digit password using the number buttons, then press ENTER. 6 To confirm your password, re-enter it using the number buttons, then press ENTER. If you make a mistake entering your password Press C before you press ENTER and input the correct number. PARENTAL CONTROL LEVEL: OFF OFF STANDARD: 8: 7: 6: 5: NC17 R PARENTAL CONTROL LEVEL: STANDARD: USA 4: PG13 54 Controlling Your TV with the Supplied Remote You can control the sound level, input source, and power switch of your Sony TV with the supplied remote. You can control your TV using the buttons below. Note Depending on the connected unit, you may not be able to control your TV using all or some of the buttons on the supplied remote. Controlling other TVs with the remote You can control the sound level, input source, and power switch of non-Sony TVs as well. If your TV is listed in the table below, set the appropriate manufacturer’s code. 1 While holding down TV [/1, press the number buttons to select your TV’s manufacturer’s code (see the table below). 2 Release TV [/1. Code numbers of controllable TVs If more than one code number is listed, try entering them one at a time until you find the one that works with your TV. ◆For RMT-D175P remote commander only By pressing You can TV [/1 Turn the TV on or off 2/VOL +/– Adjust the volume of the TV t/TV/VIDEO Switch the TV’s input source between the TV and other input sources. TV 2/VOL +/– t/TV/VIDEO Number buttons Manufacturer Code number Sony 01 (default) Aiwa 01 (default) Grundig 11 Hitachi 24 JVC 33 LG 06 Loewe 06 Panasonic 17, 49 Philips 06, 08 Samsung 06, 71 Sanyo 25 Sharp 29 Thomson 43 Toshiba 38 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 1-14 DVP-NS15/NS51P/NS43P/NS53P/K56P 55 Using Various Additional Functions ◆For RMT-D175A remote commander only Notes • When you replace the batteries of the remote, the code number you have set may be reset to the default setting. Set the appropriate code number again. • Depending on the connected unit, you may not be able to control your TV using all or some of the buttons on the supplied remote. Manufacturer Code number Sony 01 (default) Daewoo 04, 22 Hitachi 02, 04 JVC 09 LG/Goldstar 04 MGA/Mitsubishi 04, 13 Panasonic 19 Philips 21 RCA 04, 10 Samsung 04, 20 Sharp 18 Toshiba 07, 18 56 Settings and Adjustments Using the Setup Display By using the Setup Display, you can make various adjustments to items such as picture and sound. You can also set a language for the subtitles and the Setup Display, among other things. For details on each Setup Display item, see pages from 57 to 61. Note Playback settings stored in the disc take priority over the Setup Display settings and not all of the functions described may work. 1 Press DISPLAY when the player is in stop mode. The Control Menu appears. 2 Press X/x to select (SETUP), then press ENTER. The options for “SETUP” appear. 3 Press X/x to select “CUSTOM,” then press ENTER. The Setup Display appears. 4 Press X/x to select the setup item from the displayed list: “LANGUAGE SETUP,” “SCREEN SETUP,” “CUSTOM SETUP,” or “AUDIO SETUP.” Then press ENTER. The Setup item is selected. Example: “SCREEN SETUP” 5 Press X/x to select an item, then press ENTER. The options for the selected item appear. Example: “TV TYPE” ENTER DISPLAY : : STOP ( 47 ) QUICK CUSTOM RESET DVD VIDEO QUICK LANGUAGE SETUP OSD: MENU: AUDIO: SUBTITLE: ENGLISH ENGLISH ORIGINAL ENGLISH SCREEN SETUP TV TYPE: SCREEN SAVER: BACKGROUND: 16:9 ON COLOR SYSTEM (VIDEO CD): AUTO JACKET PICTURE 4:3 OUTPUT: FULL Selected item Setup items SCREEN SETUP TV TYPE: SCREEN SAVER: COLOR SYSTEM (VIDEO CD): BACKGROUND: 16:9 4:3 LETTER BOX 4:3 OUTPUT: 4:3 PAN SCAN FULL 16:9 Options 57 Settings and Adjustments 6 Press X/x to select a setting, then press ENTER. The setting is selected and setup is complete. Example: “4:3 PAN SCAN” To enter the Quick Setup mode Select “QUICK” in step 3. Follow from step 5 of the Quick Setup explanation to make basic adjustments (page 20). To reset all of the “SETUP” settings 1 Select “RESET” in step 3 and press ENTER. 2 Select “YES” using X/x. You can also quit the process and return to the Control Menu by selecting “NO” here. 3 Press ENTER. All the settings explained on pages 57 to 61 return to the default settings. Do not press [/1 while resetting the player, which takes a few seconds to complete. Setting the Display or Sound Track Language (LANGUAGE SETUP) “LANGUAGE SETUP” allows you to set various languages for the on-screen display or sound track. Select “LANGUAGE SETUP” in the Setup Display. To use the display, see “Using the Setup Display” (page 56). ◆ OSD (On-Screen Display) Switches the display language on the screen. ◆ MENU (DVD VIDEO only) You can select the desired language for the disc’s menu. ◆ AUDIO (DVD VIDEO only) Switches the language of the sound track. When you select “ORIGINAL,” the language given priority in the disc is selected. ◆ SUBTITLE (DVD VIDEO only) Switches the language of the subtitle recorded on the DVD VIDEO. When you select “AUDIO FOLLOW,” the language for the subtitles changes according to the language you selected for the sound track. z Hint If you select “OTHERS t” in “MENU,” “SUBTITLE,” or “AUDIO,” select and enter a language code from “Language Code List” on page 68 using the number buttons. Note If you select a language in “MENU,” “SUBTITLE,” or “AUDIO” that is not recorded on a DVD VIDEO, one of the recorded languages will be automatically selected. Selected setting SCREEN SETUP TV TYPE: SCREEN SAVER: BACKGROUND: 4:3 PAN SCAN ON COLOR SYSTEM (VIDEO CD): AUTO JACKET PICTURE 4:3 OUTPUT: FULL LANGUAGE SETUP OSD: MENU: AUDIO: SUBTITLE: ENGLISH ENGLISH ORIGINAL ENGLISH 58 Settings for the Display (SCREEN SETUP) Choose settings according to the TV to be connected. Select “SCREEN SETUP” in the Setup Display. To use the display, see “Using the Setup Display” (page 56). The default settings are underlined. ◆ TV TYPE Selects the aspect ratio of the connected TV (4:3 standard or wide). Note Depending on the DVD, “4:3 LETTER BOX” may be selected automatically instead of “4:3 PAN SCAN” or vice versa. ◆ COLOR SYSTEM (VIDEO CD) Selects the color system when you play a VIDEO CD. ◆ SCREEN SAVER The screen saver image appears when you leave the player in pause or stop mode for 15 minutes, or when you play a CD, or DATA CD (MP3 audio)/DATA DVD (MP3 audio) for more than 15 minutes. The screen saver will help prevent your display device from becoming damaged (ghosting). Press H to turn off the screen saver. ◆ BACKGROUND Selects the background colour or picture on the TV screen when the player is in stop mode or while playing a CD, or DATA CD (MP3 audio)/DATA DVD (MP3 audio). 16:9 Select this when you connect a wide-screen TV or a TV with a wide mode function. 4:3 LETTER BOX Select this when you connect a 4:3 screen TV. Displays a wide picture with bands on the upper and lower portions of the screen. 4:3 PAN SCAN Select this when you connect a 4:3 screen TV. Automatically displays the wide picture on the entire screen and cuts off the portions that do not fit. SCREEN SETUP TV TYPE: SCREEN SAVER: BACKGROUND: 16:9 ON COLOR SYSTEM (VIDEO CD): AUTO JACKET PICTURE 4:3 OUTPUT: FULL 16:9 4:3 LETTER BOX 4:3 PAN SCAN AUTO Outputs the video signal in the system of the VIDEO CD, either PAL or NTSC. If your TV is the DUAL system, select AUTO. PAL Changes the video signals of an NTSC VIDEO CD and outputs it in the PAL system. NTSC Changes the video signals of a PAL VIDEO CD and outputs it in the NTSC system. ON Turns on the screen saver. OFF Turns off the screen saver. JACKET PICTURE The jacket picture (still picture) appears, but only when the jacket picture is already recorded on the disc (CD- EXTRA, etc.). If the disc does not contain a jacket picture, the “GRAPHICS” picture appears. GRAPHICS A preset picture stored in the player appears. BLUE The background colour is blue. BLACK The background colour is black. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 1-15 DVP-NS15/NS51P/NS43P/NS53P/K56P 59 Settings and Adjustments ◆ 4:3 OUTPUT This setting is effective only when you set “TV TYPE” in “SCREEN SETUP” to “16:9.” Adjust this to watch 4:3 aspect ratio progressive signals. If you can change the aspect ratio on your progressive format (525p/625p) compatible TV, change the setting on your TV, not the player. This setting is effective only when “PROGRESSIVE AUTO” or “PROGRESSIVE VIDEO” is selected by using the PROGRESSIVE button on the front panel. Custom Settings (CUSTOM SETUP) Use this to set up playback related and other settings. Select “CUSTOM SETUP” in the Setup Display. To use the display, see “Using the Setup Display” (page 56). The default settings are underlined. ◆ AUTO POWER OFF Switches the Auto Power Off setting on or off. ◆ AUTO PLAY Switches the Auto Play setting on or off. This function is useful when the player is connected to a timer (not supplied). ◆ DIMMER Adjusts the lighting of the front panel display. FULL Select this when you can change the aspect ratio on your TV. NORMAL Select this when you cannot change the aspect ratio on your TV. Shows a 16:9 aspect ratio signal with black bands on left and right sides of the image. 16:9 aspect ratio TV OFF Switches this function off. ON The player enters standby mode when left in stop mode for more than 30 minutes. OFF Switches this function off. ON Automatically starts playback when the player is turned on by a timer (not supplied). BRIGHT Makes the lighting bright. DARK Makes the lighting dark. CUSTOM SETUP AUTO POWER OFF: AUTO PLAY: DIMMER: OFF OFF BRIGHT AUTO PAUSE MODE: OFF TRACK SELECTION: ON MULTI-DISC RESUME: ,continued 60 ◆ PAUSE MODE (DVD VIDEO/DVD-VR mode only) Selects the picture in pause mode. ◆ TRACK SELECTION (DVD VIDEO only) Gives the sound track which contains the highest number of channels priority when you play a DVD VIDEO on which multiple audio formats (PCM, MPEG audio, DTS, or Dolby Digital format) are recorded. Notes • When you set the item to “AUTO,” the language may change. The “TRACK SELECTION” setting has higher priority than the “AUDIO” settings in “LANGUAGE SETUP” (page 57). • If you set “DTS” to “OFF” (page 61), the DTS sound track is not played even if you set “TRACK SELECTION” to “AUTO.” • If PCM, DTS, MPEG audio, and Dolby Digital sound tracks have the same number of channels, the player selects PCM, DTS, MPEG audio, and Dolby Digital sound tracks in this order. ◆ MULTI-DISC RESUME (DVD VIDEO/ VIDEO CD only) Switches the Multi-disc Resume setting on or off. Resume playback can be stored in memory for up to 6 different DVD VIDEOs/ VIDEO CDs (page 24). Note If you run Quick Setup, Multi-disc Resume setting stored in memory may return to the default settings. Settings for the Sound (AUDIO SETUP) “AUDIO SETUP” allows you to set the sound according to the playback and connection conditions. Select “AUDIO SETUP” in the Setup Display. To use the display, see “Using the Setup Display” (page 56). The default settings are underlined. ◆ AUDIO DRC (Dynamic Range Control) (DVD VIDEO/DVD-VR mode only) Makes the sound clear when the volume is turned down when playing a DVD that conforms to “AUDIO DRC.” This function affects the output from the following jacks: – LINE OUT L/R (AUDIO) jacks – DIGITAL OUT (OPTICAL or COAXIAL) jack only when “DOLBY DIGITAL” is set to “D-PCM” (page 61). ◆ DOWNMIX (DVD VIDEO/DVD-VR mode only) Switches the method for mixing down to 2 channels when you play a DVD which has rear sound elements (channels) or is recorded in Dolby Digital format. For details on the rear signal components, see “Checking the audio signal format” (page 39). This function affects the output of the following jacks: – LINE OUT L/R (AUDIO) jacks – DIGITAL OUT (OPTICAL or COAXIAL) jack when “DOLBY DIGITAL” is set to “D-PCM” (page 61). AUTO The picture, including subjects that move dynamically, is output with no jitter. Normally select this position. FRAME The picture, including subjects that do not move dynamically, is output in high resolution. OFF No priority given. AUTO Priority given. ON Stores the resume setting in memory for up to 6 discs. OFF Does not store the resume setting in memory. Playback restarts at the resume point only for the current disc in the player. STANDARD Normally select this position. TV MODE Makes low sounds clear even if you turn the volume down. WIDE RANGE Gives you the feeling of being at a live performance. AUDIO SETUP AUDIO DRC: DIGITAL OUT: STANDARD ON DOWNMIX: DOLBY SURROUND DOLBY DIGITAL: MPEG: D-PCM PCM DTS: OFF 48kHz/96kHz PCM: 48kHz/16bit 61 Settings and Adjustments ◆ DIGITAL OUT Selects if audio signals are output via the DIGITAL OUT (OPTICAL or COAXIAL) jack. Setting the digital output signal Switches the method of outputting audio signals when you connect a component such as an amplifier (receiver) or MD deck with a digital input jack. For connection details, see page 18. Select “DOLBY DIGITAL,” “MPEG,” “DTS,” and “48kHz/96kHz PCM” after setting “DIGITAL OUT” to “ON.” If you connect a component that is incompatible with the selected audio signal, a loud noise (or no sound) may be heard from the speakers, risking damage to your ears or speakers. ◆ DOLBY DIGITAL (DVD VIDEO/DVD-VR mode only) Selects the type of Dolby Digital signal. ◆ MPEG (DVD VIDEO/DVD-VR mode only) Selects the type of MPEG audio signal. ◆ DTS Selects whether or not to output DTS signals. ◆ 48kHz/96kHz PCM (DVD VIDEO only) Selects the sampling frequency of the audio signal. Note The analogue audio signals from the LINE OUT L/ R (AUDIO) jacks are not affected by this setting and keep their original sampling frequency level. DOLBY SUR- ROUND Normally, select this position. Multi-channel audio signals are output to 2 channels for enjoying surround sounds. NORMAL Multi-channel audio signals are downmixed to 2 channels for use with your stereo. ON Normally select this position. When you select “ON,” see “Setting the digital output signal” for further settings. OFF The influence of the digital circuit upon the analog circuit is minimal. D-PCM Select this when the player is connected to an audio component without a built-in Dolby Digital decoder. You can select whether the signals conform to Dolby Surround (Pro Logic) or not by making adjustments to the “DOWNMIX” item in “AUDIO SETUP” (page 60). DOLBY DIGITAL Select this when the player is connected to an audio component with a built-in Dolby Digital decoder. PCM Select this when the player is connected to an audio component without a built-in MPEG decoder. If you play multi-channel MPEG audio sound tracks, only the Front (L) and Front (R) signals will be output from your two front speakers. MPEG Select this when the player is connected to an audio component with a built-in MPEG decoder. OFF Select this when the player is connected to an audio component without a built-in DTS decoder. ON Select this when the player is connected to an audio component with a built-in DTS decoder. 48kHz/16bit The audio signals of DVD VIDEOs are always converted to 48kHz/16bit. 96kHz/24bit All types of signals including 96kHz/24bit are output in their original format. However, if the signal is encrypted for copyright protection purposes, the signal is only output as 48kHz/16bit. 62 Additional Information Troubleshooting If you experience any of the following difficulties while using the player, use this troubleshooting guide to help remedy the problem before requesting repairs. Should any problem persist, consult your nearest Sony dealer. Power The power is not turned on. , Check that the mains lead is connected securely. Picture There is no picture/picture noise appears. , Re-connect the connecting cord securely. , The connecting cords are damaged. , Check the connection to your TV (page 15) and switch the input selector on your TV so that the signal from the player appears on the TV screen. , The disc is dirty or flawed. , If the picture output from your player goes through your VCR to get to your TV or if you are connected to a combination TV/ VIDEO player, the copy-protection signal applied to some DVD programmes could affect picture quality. If you still experience problems even when you connect your player directly to your TV, try connecting your player to your TV’s S VIDEO input (page 15). , The disc is recorded in a colour system that is different from your TV. , If your player connect to COMPONENT VIDEO OUT jacks, and you have selected “PROGRESSIVE AUTO” or “PROGRESSIVE VIDEO” using the PROGRESSIVE button on the front panel (the PROGRESSIVE indicator lights up) even though your TV cannot accept the progressive signal. In this case, select “NORMAL (INTERLACE)” so that the PROGRESSIVE indicator turns off. , If the colour system of your player does not match with that of your TV, change the colour system of the player. For details, see page 16. (You cannot change the colour system of the DVD disc itself.) , Even if your player connect to COMPONENT VIDEO OUT jacks, and your TV is compatible with progressive format 525p/625p signals, the image may be affected when you set the player to progressive format. In this case, select “NORMAL (INTERLACE)” using the PROGRESSIVE button on the front panel so that the PROGRESSIVE indicator turns off and the player is set to normal (interlace) format. , If your player is connected to the LINE OUT or S VIDEO OUT jacks and no picture appears, press the PROGRESSIVE button repeatedly until the picture appears. The picture does not fill the screen, even though the aspect ratio is set in “TV TYPE” under “SCREEN SETUP.” , The aspect ratio of the disc is fixed on your DVD. Sound There is no sound. , Re-connect the connecting cord securely. , The connecting cord is damaged. , The player is connected to the wrong input jack on the amplifier (receiver) (page 18). , The amplifier (receiver) input is not correctly set. , The player is in pause mode or in Slow- motion Play mode. , The player is in fast forward or fast reverse mode. , If the audio signal does not come through the DIGITAL OUT (OPTICAL or COAXIAL) jack, check the audio settings (page 61). , While playing a Super VCD on which the audio track 2 is not recorded, no sound will come out when you select “2:STEREO,” “2:1/L,” or “2:2/R.” , When playing multichannel MPEG audio soundtracks, only the Front (L) and Front (R) signals will be output from two front speakers. The sound volume is low. , The sound volume is low on some DVDs. The sound volume may improve if you set “AUDIO DRC” in “AUDIO SETUP” to “TV MODE” (page 60). www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 1-16 DVP-NS15/NS51P/NS43P/NS53P/K56P 63 Additional Information Operation The remote does not function. , The batteries in the remote are weak. , There are obstacles between the remote and the player. , The distance between the remote and the player is too far. , The remote is not pointed at the remote sensor on the player. The disc does not play. , The disc is turned over. Insert the disc with the playback side facing down. , The disc is skewed. , The player cannot play certain discs (page 6). , The region code on the DVD does not match the player. , Moisture has condensed inside the player (page 3). , The player cannot play a recorded disc that is not correctly finalized (page 7). The MP3 audio track cannot be played (page 46). , The DATA CD is not recorded in an MP3 format that conforms to ISO 9660 Level 1/ Level 2 or Joliet. , The DATA DVD is not recorded in MP3 format that conforms to UDF (Universal Disk Format). , The MP3 audio track does not have the extension “.MP3.” , The data is not formatted in MP3 even though it has the extension “.MP3.” , The data is not MPEG-1 Audio Layer III data. , The player cannot play audio tracks in mp3PRO format. , “MODE (MP3, JPEG)” is set to “IMAGE (JPEG)” (page 49). The JPEG image file cannot be played (page 46). , The DATA CD is not recorded in a JPEG format that conforms to ISO 9660 Level 1/ Level 2, or Joliet. , The DATA DVD is not recorded in JPEG format that conforms to UDF (Universal Disk Format). , The file has an extension other than “.JPEG” or “.JPG.” , The image is larger than 3072 (width) × 2048 (height) in normal mode, or more than 3,300,000 pixels in progressive JPEG. (Some progressive JPEG files cannot be displayed even if the file size is within this specified capacity.) , The image does not fit the screen (the image is reduced). , “MODE (MP3, JPEG)” is set to “AUDIO (MP3)” (page 49). The MP3 audio tracks and JPEG image files start playing simultaneously. , “MODE (MP3, JPEG)” is set to “AUTO” (page 49). The album/track/file names are not displayed correctly. , The player can only display numbers and alphabet. Other characters are displayed as “*”. The disc does not start playing from the beginning. , Programme Play, Shuffle Play, Repeat Play, or A-B Repeat Play is selected (page 27). , Resume play has taken effect (page 24). The player starts playing the disc automatically. , The disc features an auto playback function. , “AUTO PLAY” in “CUSTOM SETUP” is set to “ON” (page 59). Playback stops automatically. , While playing discs with an auto pause signal, the player stops playback at the auto pause signal. Some functions such as Stop, Fast Play and Slow Play, Slow-motion Play, Repeat Play, Shuffle Play, or Programme Play cannot be performed. , Depending on the disc, you may not be able to do some of the operations above. Refer to the operating manual that comes with the disc. The language for the sound track cannot be changed. , Try using the DVD’s menu instead of the direct selection button on the remote (page 25). ,continued 64 , Multilingual tracks are not recorded on the DVD being played. , The DVD prohibits the changing of the language for the sound track. The subtitle language cannot be changed or turned off. , Try using the DVD’s menu instead of the direct selection button on the remote (page 25). , Multilingual subtitles are not recorded on the DVD being played. , The DVD prohibits the changing of subtitles. The angles cannot be changed. , Try using the DVD’s menu instead of the direct selection button on the remote (page 25). , Multi-angles are not recorded on the DVD being played. , The angle can only be changed when the “ ” indicator lights up on the front panel display (page 9). , The DVD prohibits changing of the angles. The player does not operate properly. , When static electricity, etc., causes the player to operate abnormally, unplug the player. 5 numbers or letters are displayed on the screen and on the front panel display. , The self-diagnosis function was activated. (See the table on page 65.) The disc tray does not open and “LOCKED” appears on the front panel display. , Child Lock is set (page 23). The disc tray does not open and “TRAY LOCKED” appears on the front panel display. , Contact your Sony dealer or local authorized Sony service facility. “Data error” appears on the TV screen when playing a DATA CD or DATA DVD. , The MP3 audio track/JPEG image file you want to play is broken. , The data is not MPEG-1 Audio Layer III data. , The JPEG image file format does not conform to DCF (page 45). , The JPEG image file has the extension “.JPG” or “.JPEG,” but is not in JPEG format. 65 Additional Information Self-diagnosis Function (When letters/numbers appear in the display) When the self-diagnosis function is activated to prevent the player from malfunctioning, a five-character service number (e.g., C 13 50) with a combination of a letter and four digits appears on the screen and the front panel display. In this case, check the following table. Glossary Album (page 45, 47) A unit in which to store JPEG image files or MP3 audio tracks on a DATA CD/DATA DVD. (“Album” is an exclusive definition for this player.) Chapter (page 9) Sections of a picture or a music feature that are smaller than titles. A title is composed of several chapters. Depending on the disc, no chapters may be recorded. Dolby Digital (page 19, 61) Digital audio compression technology developed by Dolby Laboratories. This technology conforms to multi-channel surround sound. The rear channel is stereo and there is a discrete subwoofer channel in this format. Dolby Digital provides the same discrete channels of high quality digital audio found in “Dolby Digital” theatre surround sound systems. Good channel separation is realized because all of the channel data is recorded discretely and little deterioration is realized because all channel data processing is digital. DTS (page 19, 61) Digital audio compression technology that Digital Theater Systems, Inc. developed. This technology conforms to multi-channel surround sound. The rear channel is stereo and there is a discrete subwoofer channel in this format. DTS provides the same discrete channels of high quality digital audio. Good channel separation is realized because all of the channel data is recorded discretely and little deterioration is realized because all channel data processing is digital. DVD VIDEO (page 5) A disc that contains up to 8 hours of moving pictures even though its diameter is the same as a CD. The data capacity of a single-layer and single- sided DVD is 4.7 GB (Giga Byte), which is 7 times that of a CD. The data capacity of a double-layer and single-sided DVD is 8.5 GB, a single-layer and double-sided DVD is First three characters of the service number Cause and/or corrective action C 13 The disc is dirty or recorded in a format that this player cannot play (page 6). ,Clean the disc with a cleaning cloth or check its format (page 2). C 31 The disc is not inserted correctly. ,Re-insert the disc correctly. E XX (xx is a number) To prevent a malfunction, the player has performed the self-diagnosis function. ,Contact your nearest Sony dealer or local authorized Sony service facility and give the 5- character service number. Example: E 61 10 C:13:50 ,continued 66 9.4 GB, and double-layer and double-sided DVD is 17 GB. The picture data uses the MPEG 2 format, a worldwide standard of digital compression technology. The picture data is compressed to about 1/40 (average) of its original size. The DVD also uses a variable rate coding technology that changes the data to be allocated according to the status of the picture. Audio information is recorded in a multi-channel format, such as Dolby Digital, allowing you to enjoy a more realistic audio presence. Furthermore, various advanced functions such as the multi-angle, multilingual, and Parental Control functions are provided with the DVD. DVD-RW (page 5) A DVD-RW is a recordable and rewritable disc that is the same size as a DVD VIDEO. The DVD-RW has two different modes: VR mode and Video mode. DVD-RWs created in Video mode have the same format as a DVD VIDEO, while discs created in VR (Video Recording) mode allow the contents to be programmed or edited. DVD+RW (page 5) A DVD+RW (plus RW) is a recordable and rewritable disc. DVD+RWs use a recording format that is comparable to the DVD VIDEO format. File (page 45, 48) A JPEG image recorded on a DATA CD/ DATA DVD (“File” is an exclusive definition for this player.) A single file consists of a single image or movie. Film based software, Video based software (page 17) DVDs can be classified as Film based or Video based software. Film based DVDs contain the same images (24 frames per second) that are shown at movie theatres. Video based DVDs, such as television dramas or sit-coms, displays images at 30 frames/60 fields (25 frames/50 fields) per second. MPEG audio (page 19, 61) International standard coding system used to compress audio digital signals authorized by ISO/IEC. MPEG 1 conforms to up to 2- channel stereo. MPEG 2, used on DVDs, conforms to up to 7.1-channel surround. Normal (Interlace) format (page 17) Normal (Interlace) format shows every other line of an image as a single “field” and is the standard method for displaying images on television. The even number field shows the even numbered lines of an image, and the odd numbered field shows the odd numbered lines of an image. Progressive format (page 17) Compared to the Interlace format that alternately shows every other line of an image (field) to create one frame, the Progressive format shows the entire image at once as a single frame. This means that while the Interlace format can show 25 or 30 frames (50-60 fields) in one second, the Progressive format can show 50-60 frames in one second. The overall picture quality increases and still images, text, and horizontal lines appear sharper. This player is compatible with the 525 or 625 progressive format. Progressive JPEG Progressive JPEGs are used mostly on the internet. They are different from other JPEGs in that they “fade in” gradually instead of being drawn from top to bottom when displayed on a browser. This lets you view the image while it is being downloaded. Title (page 9) The longest section of a picture or music feature on a DVD, movie, etc., in video software, or the entire album in audio software. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 1-17 DVP-NS15/NS51P/NS43P/NS53P/K56P 67 Additional Information Specifications System Laser: Semiconductor laser Signal format system: PAL/NTSC (See page 16 to switch) Audio characteristics Frequency response: DVD VIDEO (PCM 48 kHz): 2 Hz to 22 kHz (±0.5 dB)/ CD: 2 Hz to 20 kHz (±0.5 dB) Signal-to-noise ratio (S/N ratio): 115 dB (LINE OUT L/R (AUDIO) jacks only) Harmonic distortion: 0.01 % Dynamic range: DVD VIDEO: 85 dB/ CD: 85 dB Wow and flutter: Less than detected value (±0.001% W PEAK) Outputs (Jack name: Jack type/Output level/Load impedance) LINE OUT (AUDIO): Phono jack/2 Vrms/ 10 kilohms DIGITAL OUT (OPTICAL): Optical output jack/–18 dBm (wave length 660 nm) DIGITAL OUT (COAXIAL): Phono jack/ 0.5 Vp-p/75 ohms COMPONENT VIDEO OUT (Y, PB/CB, PR/CR): Phono jack/Y: 1.0 Vp-p, PB/CB, PR/ CR: 0.7 Vp-p/75 ohms LINE OUT (VIDEO): Phono jack/1.0 Vp-p/ 75 ohms S VIDEO OUT: 4-pin mini DIN/ Y: 1.0 Vp-p, C: 0.3 Vp-p (PAL), 0.286 Vp-p (NTSC)/75 ohms General Power requirements: Taiwan model: 110 V AC, 60 Hz Model for other areas: 110 – 240 V AC, 50/60 Hz See page 2 for further information. Power consumption: 9 W Dimensions (approx.): 430 × 43 × 208.8 mm (width/height/ depth) incl. projecting parts Mass (approx.): 1.74 kg Operating temperature: 5 ° C to 35 ° C Operating humidity: 25 % to 80 % Supplied accessories See page 14. Specifications and design are subject to change without notice. ENERGY STARR is a U.S. registered mark. As an ENERGY STARR Partner, Sony Corporation has determined that this product meets the ENERGY STARR guidelines for energy efficiency. 1-17E www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 2-1 DVP-NS15/NS51P/NS43P/NS53P/K56P Note: Follow the disassembly procedure in the numerical order given. 2-1. UPPER CASE SECTION 2 DISASSEMBLY 2-2. FRONT PANEL ASSEMBLY, SWITCH BOARD and MC BOARD a). (DVP-NS43P/NS53P) 4 Two Tapping Screws 3 Tray Cover 5 Three Tapping Screws 2 1 Chassis Back 5 Claw 1 Claw 4 Claw 2 Claw 8 Front Panel Assembly e 3 Claw 6 FSW-001 Flat Flexible Cable (CN001, 7P) 7 Three Screws +BVTP2.6 (3CR) 9 SW-468 Board e www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 2-2 DVP-NS15/NS51P/NS43P/NS53P/K56P b ) . (DVP-NS15) 5 Claw 1 Claw 4 Claw 2 Claw 8 Front Panel Assembly e e 3 Claw 6 FSW-002 Flat Flexible Cable (CN002, 9P) 7 Two Screws +BVTP2.6 (3CR) 9 SW-467 Board c). (DVP-K56P) 6 Claw 2 Claw 5 Claw 3 Claw 9 Front Panel Assembly e j j e 4 Claw 7 FSW-001 Flat Flexible Cable (CN051, 7P) 8 MC-089 Harness (CN501, 6P) qs Two Screws +BVTP2.6 (3CR) q; Two Screws +BVTP2.6 (3CR) qd SW-469 Board qa MC-161 Board 1 One Screw +BV3 (3-CR) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 2-3 DVP-NS15/NS51P/NS43P/NS53P/K56P 2-3. LOADING ASSEMBLY a). (DVP-NS43P/NS53P/NS51P) a a 4 Three Screws +BV3 (3-CR) 5 Loading Assembly 3 FMS-010 Flat Flexible Cable (CN202, 5P) 1 FMO-009 Flat Flexible Cable (CN101, 24P) 2 MD-111 Harness (CN201, 6P) d). (DVP-NS51P) 5 Claw 1 Claw 4 Claw 2 Claw 7 Front Panel Assembly e e 3 Claw 8 Two Screws +BVTP2.6 (3CR) 9 SW-475 Board 6 FSW-002 Flat Flexible Cable (CN002, 9P) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 2-4 DVP-NS15/NS51P/NS43P/NS53P/K56P c). (DVP-K56P) a a 4 Three Screws +BV3 (3-CR) 5 Loading Assembly 1 FMO-009 Flat Flexible Cable (CN101, 24P) 3 FMS-010 Flat Flexible Cable (CN202, 5P) 2 MD-111 Harness (CN201, 6P) b). (DVP-NS15) a a 4 Three Screws +BV3 (3-CR) 5 Loading Assembly 3 FMS-010 Flat Flexible Cable (CN202, 5P) 1 FMO-009 Flat Flexible Cable (CN101, 24P) 2 MD-111 Harness (CN201, 6P) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 2-5 DVP-NS15/NS51P/NS43P/NS53P/K56P 2-4. OPTICAL PICK-UP (DEVICE, OPTICAL KHM-313CAA/C2RP) Caution Point on the Laser Diode: Laser Diode in the optical Device is very sensitive to Surge Current or ElectroStatic Discharge (ESD): After take-out FMO-009 Flat Flexible Cable from CN101 of MV-47/MV-48 board immediately ground FMO-009 Flat Flexible Cable pattern using short clip. Metal paper clip can be used as short clip. Shortland Position Note: Solder shortland before remove the FMO-009 Flat Flaxible Cable from 24 pin BU connector. 5 FMO-009 Flat Flexible Cable (CN101, 24P) 4 MD-111 Harness (CN201, 6P) 1 Four Insulator Screws 6 Two Insulator 6 Two Insulator 3 Optical Device (KHM-313CAA/C2RP) 2 FFC Holder www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 2-6 DVP-NS15/NS51P/NS43P/NS53P/K56P 2-5. REAR PANEL, MV BOARD and IF BOARD a). (NS43P/NS53P/NS51P) 4 FMS-010 Flat Flexible Cable (CN202, 5P) 6 FMO-009 Flat Flexible Cable (CN101, 24P) 9 MV-47 Board 5 MD-111 Harness (CN201, 6P) 7 PM-127 Harness (CN501, 10P) 8 Five Screws +BV3 (3-CR) 2 Three Screws +BV3 (3-CR) 3 Rear Panel 1 Tapping Screw a a o l DVP-NS51P qs IF-144 Board DVP-NS43P/NS53P qa FSW-001 Flat Flexible Cable (CN403, 7P) q; Three Screws +BV3 (3-CR) q; Three Screws +BV3 (3-CR) qs IF-145 Board qa FSW-002 Flat Flexible Cable (CN403, 9P) Note: Caution Point on the PWB IF-143/IF-144 and IF-145 When handling IF-143/IF-144 and IF-145 PWB avoid contact with the sharp metal edge on the top side of Vacuum Fluorescent Display (ND401). www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 2-7 DVP-NS15/NS51P/NS43P/NS53P/K56P b). (DVP-NS15) 4 FMS-010 Flat Flexible Cable (CN202, 5P) 6 FMO-009 Flat Flexible Cable (CN101, 24P) 9 MV-48 Board 5 MD-111 Harness (CN201, 6P) 7 PM-127 Harness (CN501, 10P) 8 Five Screws +BV3 (3-CR) 2 Three Screws +BV3 (3-CR) 3 Rear Panel 1 Tapping Screw qs IF-143 Board a a qa FSW-002 Flat Flexible Cable (CN403, 9P) 9 q; Two Screws +BV3 (3-CR) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 2-8 DVP-NS15/NS51P/NS43P/NS53P/K56P c). (DVP-K56P) 4 FMS-010 Flat Flexible Cable (CN202, 5P) 0 MC-089 Harness (CN404, 6P) 6 FMO-009 Flat Flexible Cable (CN101, 24P) 9 MV-47 Board 5 MD-111 Harness (CN201, 6P) 7 PM-127 Harness (CN501, 10P) 8 Five Screws +BV3 (3-CR) 2 Three Screws +BV3 (3-CR) 3 Rear Panel 1 Tapping Screw qs IF-144 Board a a b qa FSW-001 Flat Flexible Cable (CN403, 7P) o l q; Three Screws +BV3 (3-CR) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 2-9 DVP-NS15/NS51P/NS43P/NS53P/K56P 2-6. SWITCHING REGULATOR 2 Two Screws +BV3 (3-CR) 1 Connector (PM-127 Harness, CN201, 10P) 3 Power Board www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 2-10 DVP-NS15/NS51P/NS43P/NS53P/K56P 2-7. INTERNAL VIEWS MS-203 MOUNT Optical Pick-Up (Device, Optical KHM-313CAA/C2RP/ Service Assembly) TOP VIEW BOTTOM VIEW www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 2-11 DVP-NS15/NS51P/NS43P/NS53P/K56P 2-8. CIRCUIT BOARDS LOCATION a). (NS51P/NS43P/NS53P) IF-144 Board (EXCEPT DVP-NS51P) (INTERFACE) SW-468 Board (EXCEPT DVP-NS51P) (SWITCH) MV-47 Board (CPU, Servo-DSP, AVDEC, DRIVE, VIDEO, AUDIO, POWER) Power Board b). (DVP-NS15) IF-143 Board (INTERFACE) SW-467 Board (SWITCH PWB) MV-48 Board (CPU, Servo-DSP, AVDEC, DRIVE, VIDEO D-EURO, AUDIO_EURO (D), POWER) Power Board www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 2-12 DVP-NS15/NS51P/NS43P/NS53P/K56P 2-12E c). (DVP-K56P) IF-144 Board (INTERFACE) MC-161 Board (MIC-ECHO) SW-469 Board (SWITCH BOARD) MV-47 Board (CPU, Servo-DSP, AVDEC, DRIVE, VIDEO, AUDIO, POWER) Power Board d). (DVP-NS51P) IF-145 Board (DVP-NS51P ONLY) (INTERFACE) SW-475 Board (DVP-NS51P ONLY) (SWITCH) MV-47 Board (CPU, Servo-DSP, AVDEC, DRIVE, VIDEO, AUDIO, POWER) Power Board www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DVP-NS15/NS51P/NS43P/NS53P/K56P SECTION 3 BLOCK DIAGRAMS 3-1. OVERALL BLOCK DIAGRAM 3-1 3-2 FLASH MEMORY EEPROM RESET IC P-CONT O/I POWER TRANSFORMER SECONDARY PRIMARY SW+8V SW+5V SW+3.3V EVER-10V EVER+5V EVER+5V FOCUS TRACKING COIL DRIVE SPINDLE/SLED /LOADING MOTOR DRIVE IC401 AUDIO AMPLIFIER MUTE DRIVER AUDIO AMPLIFIER VIDEO BUFFER MICROPROCESSOR RF AMP SERIAL BUS 3.3V REGULATOR IC VFD DRIVER CIRCUIT LED KEY FUNCTION SW-10V SWITCHING REGULATOR SRV1872WW (Except DVP-NS53P:MX) SRV1873UC (DVP-NS53P:MX) EVER +5V SPINDLE MOTOR SLED MOTOR M M M LOADING MOTOR DVD / CD PDIC FOCUS COIL TRACKING COIL CHUCK/TRAY DETECT INLIMIT SENSOR Vkk EVER 3.3V IF-143 BOARD (DVP-NS15 ONLY) (SEE PAGE 3-21to 3-22) IF-144 BOARD (DVP-NS43P/NS53P/K56P) (SEE PAGE 3-19 to 3-20) IF-145 BOARD (DVP-NS51P ONLY) (SEE PAGE 3-19 to 3-20) SW-468 BOARD (DVP-NS43P/NS53P ONLY) (SEE PAGE 3-19 to 3-20) SW-469 BOARD (DVP-K56P ONLY) (SEE PAGE 3-19 to 3-20) SW-467 BOARD (DVP-NS15 ONLY) (SEE PAGE 3-21 to 3-22) SW-475 BOARD (DVP-NS51P ONLY) (SEE PAGE 3-19 to 3-20) BASE UNIT (DEVICE, OPTICAL KHM-313CAA/C2RP) POWER LINE (SEE PAGE 3-3 to 3-4) *EXCEPT DVP-NS15/NS51P EXCEPT DVP-NS15 MV-47 BOARD (EXCEPT DVP-NS15) (SEE PAGE 3-5 to 3-6) MV-48 BOARD (DVP-NS15 ONLY) (SEE PAGE 3-7 to 3-8) IC201 IC101 IC102 IC103 RESET IC IC408 IR RECEIVER IC001 LED KEY FUNCTION IR RECEIVER VFD ND401 IC407 IF MICON IC404 IC304 IC108 SDRAM IC104 IC406 EXCEPT DVP-NS15 DVP-NS15 ONLY CN301 AUDIO/VIDEO OUTPUT J301 AUDIO/VIDEO OUTPUT EXCEPT DVP-NS15 IC402 7 1 6 2 MIC AMP ECHO SET R532 R530 IC503 IN ECHO OUT IC504 MUTE DRIVER Q503, Q505 MIC DETE CT Q501, Q502 7 1 5 2 MIC AMP IC502 MC-161 BOARD (DVP-K56P ONLY) (SEE PAGE 3-15 to 3-16) 2 9 MIC VR R501 DVP-K56P ONLY Notes: MV-47/MV-48 mounted PWB must be replaced if IC103 (EEPROM IC) is damaged or not functioning. The old MV-47/MV-48 mounted PWB must be completely disposed. • Abbreviation AEP : AEP Model AR : Argentina Model AUS : Australia/New Zealand Model BR : Brazilian Model CH : Chinese Model E : Latin America Model EA : Saudi Arabia Model HK : Hong Kong Model IN : India Model IR : Iran Model KR : Korean Model ME2 : Middle East Model ME5 : IND,PAK,MAR Model MX : Mexican Model MY : Malaysian Model RUS : Russian Model SP : Singapore Model TW : Taiwan Model UK : UK Model VN : Vietnam Model w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DVP-NS15/NS51P/NS43P/NS53P/K56P 3-2. POWER LINE BLOCK DIAGRAM Transformer PC101 Photo Coupler GND FG001 IC611 Shunt Reg L312 P312 SW801 L512 D511 D311 L211 Q211 Q712 Q311 P.CONT SW-10V SW + 5V SW + 3.3V AU-10V CN106 CN401 11 CN101 CN403 CN001 CN403 CN002 VCC OPTICAL DEVICE EVER + 5V POWER EVER-10V SW+5V SW+3.3V EVER+5V EVER+11V AU+11V SW+8V CN501 CN201 Q611 D411 D211 2 Line fiters D S C Bridge Rectifier Diode F101 CN101 L101, L102 ACIN 1 2 T101 3 1 8 9 10 15 13 11 12 15 6 5 4 3 1 8 9 10 6 5 4 PS501 P311 POWER BOARD (SRV1872WW) (EXCEPT DVP-NS53P: MX) (SRV1873UC) (DVP-NS53P: MX ONLY) (SEE PAGE 4-XX to 4-XX) MV-47 BOARD (EXCEPT DVP-NS15) (SEE PAGE 4-XX to 4-XX) MV-48 BOARD (DVPNS15 ONLY) (SEE PAGE 4-XX to 4-XX) PS502 Video Buffer IC304 3.3V Reg IC105/7 MTK IC IC101 1.8V Reg IC110 SDRAM IC104 EEPROM IC103 RESET IC IC108 Coaxial Q411 Optical Out IC405 FLASH ROM IC102 MUTE DRIVER D401 Q501 -5V Reg IC303 +5V Reg IC403 Motor Driver IC201 FLD ND401 F1 F2 VKK DC-DC CONV Audio Buffer IC401/IC402 Q401 Q416 IPD IC101 13 T401 IR RECEIVER IC407 RESET IC IC408 3.3V Reg IC IC407 IF MICON IC404 PLAY LED Q401,402 DVP-NS43P/NS53P/K56P EXCEPT DVP-NS15 IF-143 BOARD (DVP-NS15 ONLY) (SEE PAGE 4-XX to 4-XX) IF-144 BOARD (DVP-NS43P/NS53P/K56P) (SEE PAGE 4-XX to 4-XX) IF-145 BOARD (DVP-NS51P ONLY) (SEE PAGE 4-XX to 4-XX) SW-468 BOARD (DVP-NS43P/NS53P ONLY) (SEE PAGE 4-XX to 4-XX) SW-469 BOARD (DVP-K56P ONLY) (SEE PAGE 4-XX to 4-XX) SW-10V EVER+5V SW+3.3V PCONT 7 5 3 PROG LED IC407 DVP-NS45/NS55/NS61P ONLY SW-475 BOARD (DVP-NS51P ONLY) (SEE PAGE 4-XX to 4-XX) PROG LED IR RECEIVER IC001 5 3 5 GND FG002 11 12 EXCEPT DVP-NS15 3 5 IR RECEIVER IC001 SW-467 BOARD (DVP-NS15 ONLY) (SEE PAGE 4-XX to 4-XX) L411 The components identified by mark or dotted line with mark are critical for safety. Replace only with part number specified. 3-3 3-4 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DVP-NS15/NS51P/NS43P/NS53P/K56P 3-3. SYSTEM CONTROL/SIGNAL PROCESSOR (1) BLOCK DIAGRAM 137 139~142,144,148~150,152~155 CXD9197R MICROPROCESSOR AV DECODER SERVO DSP 64M SDRAM 16M ROM RAO~RA11 47,49~55,57,60,62~69,72,86 AO~A20 110~114,116~119,121~122,124~126 RDO-RD15 75~81,85 HDO – HD7 DQM1 DQMO BA1 SCL SDA 109 129 136 BA0 134 RAS 132 CAS 131 RWE 135 RCS 146 DRCLK 147 CKE 95 105 94 92 100 91 IFSCK IFSDO IFBSY 59 70 73 XWR XROMCS XRD IFSDI XSYSRST XIFCS SPDIF XMAMUTE 165 170 XMAMUTE SPDIF AR XA MUTE AL 187 189 AR AL WIDE EUROVY XV MUTE DISC/EXT COMP/MUTE CVBS SY/Y/G Sc/Cb/B C_/R 169 166 167 163 175 179 181 182 WIDE EUROVY DISC/XEXT COMP_MUTE CVBS Y/G B/Cb/Pb R/Cr/Pr 194 193 XTALI XTALO 96 98 6 5 IC103 EEPROM SCL SDA CN 106 VIDEO (2) (SEE PAGE 3-13 TO 3-14) AUDIO (1) (SEE PAGE 3-15 TO 3-16) IFBSY IFSCK IFSDO XIFCS IFSDI XSYSRST XA MUTE XV MUTE 9 5 7 4 6 2 14 10 MV-47 BOARD (EXCEPT DVP-NS15) (SEE PAGE 4-27 to 4-28) XECHO 164 XECHO KRMOD 162 KRMOD MIC 161 MIC TO INTERFACE CONTROL (1) (SEE PAGE 3-19 TO 3-20) 0.7Vp-p 27MHz 1.9Vp-p H 0.7Vp-p H 286 mVp-p (NTSC) 300 mVp-p (PAL) H 1Vp-p H 1Vp-p H 3.3Vp-p 110MHz X102 IC101 IC104 IC102 IC101 10 146 IC101 9 193 IC101 8 182 IC101 7 181 IC101 C/BAR PB 5 175 IC101 C/BAR PB 4 179 IC101 C/BAR PB 3 181 1Vp-p H IC101 C/BAR PB 6 179 MV-47 Line Out/S-Video Out LINE OUT/S-VIDEO OUT COMPONENT OUT 3-5 3-6 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DVP-NS15/NS51P/NS43P/NS53P/K56P 3-4. SYSTEM CONTROL/SIGNAL PROCESSOR (2) BLOCK DIAGRAM 137 139~142,144,148~150,152~155 CXD9197R MICROPROCESSOR AV DECODER SERVO DSP 64M SDRAM 16M ROM RAO~RA11 47,49~55,57,60,62~69,72,86 AO~A20 110~114,116~119,121~122,124~126 RDO-RD15 75~81,85 HDO – HD7 DQM1 DQMO BA1 SCL SDA 109 129 136 BA0 134 RAS 132 CAS 131 RWE 135 RCS 146 DRCLK 147 CKE 95 105 94 92 100 91 IFSCK IFSDO IFBSY 59 70 73 XWR XROMCS XRD IFSDI XSYSRST XIFCS SPDIF XMAMUTE 165 170 XMAMUTE SPDIF AR XA MUTE AL 187 189 AR AL WIDE EUROVY XV MUTE RGBSEL DISC/EXT COMP/MUTE CVBS SY/Y/G Sc/Cb/B C_/R 169 166 167 163 175 179 181 182 WIDE EUROVY DISC/XEXT COMP_MUTE CVBS Y/G B/Cb/Pb R/Cr/Pr 194 193 XTALI XTALO 96 98 6 5 IC103 EEPROM SCL SDA CN 106 VIDEO (1) (SEE PAGE 3-11 TO 3-12) AUDIO (2) (SEE PAGE 3-17 TO 3-18) IFBSY IFSCK IFSDO XIFCS IFSDI XSYSRST XA MUTE XV MUTE 9 5 7 4 6 2 14 10 MV-48 BOARD (DVP-NS15 ONLY) (SEE PAGE 4-39 to 4-40) XECHO 164 XECHO DSEL 162 DSEL 161 RGBSEL TO INTERFACE CONTROL (2) (SEE PAGE 3-21 TO 3-22) 286 mVp-p (NTSC) 300 mVp-p (PAL) H 1Vp-p H 1Vp-p H IC101 C/BAR PB VIDEO/RGB MODE 5 175 IC101 C/BAR PB 4 179 IC101 C/BAR PB 3 181 S-VIDEO MODE RGB MODE 27MHz 1.9Vp-p 3.3Vp-p 110MHz X102 IC101 IC104 IC102 IC101 10 146 IC101 9 193 0.7Vp-p 0.7Vp-p 0.7Vp-p IC101 RGB MODE 8 182 IC101 7 181 IC101 C/BAR PB 6 179 3-7 3-8 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DVP-NS15/NS51P/NS43P/NS53P/K56P 3-5. RF/SERVO BLOCK DIAGRAM MV-47 BOARD (EXCEPT DVP-NS15) (SEE PAGE 4-27 to 4-28) MV-48 BOARD (DVP-NS15 ONLY) (SEE PAGE 4-39 to 4-40) BASE UNIT (DEVICE, OPTICAL KHM-313CAA/C2RP) SPINDLE MOTOR SLED MOTOR LIMIT DETECT CN201 10 13 15 4 1 D01+ D01- D02+ D02- D05+ D05- 22 23 20 21 18 19 MDI2 MDI1 LD01 TSD_M MUTE MUTE123 SPFG TROPENPWM DMO FMO TRO FOO LD02 6 DVDRFIP TPI TNI 46 45 OCSW CKSW 82 LIMITSW IN1- IN2- IN3- IN4- CTL 20 22 MUTE4 TSD_M 7 19 21 6 45 OPO RES1 RES2 MUTE123 PS MOTOR DRIVER IC LDM+ LDM- OKSW1 OCSW1 FCS- FCS+ TRK+ TRK- LD (780) LD (650) PD RF F E M001 LOADING MOTOR S001 CHUCK/TRAY DETECT FOCUS COIL TRACKING COIL DVD/CD LD MODULE CN202 2~5 8~11 C D A B DVD/CD PDIC 157 FWD 158 99 103 159 43 39 37 38 41 42 REV 16 FWD 17 REV IC101 6 (CD PB) 1 IC101 6 (DVD PB) 2 200nsec 100nsec 24 23 22 21 6 2 5 14 10 17 20 19 16 15 CN101 5 4 2 1 1 2 5 6 3 1 2 4 5 MS-203 BOARD (SEE PAGE 4-16) D04+ D04- D03+ D03- SP- SP+ SL- SL+ LIMIT (0.5Vp-p to 1.1Vp-p) (0.65Vp-p to 1.48Vp-p) 36 37 34 24 25 35 27 28 29 30 IC201 RF AMPLIFIER IC101 (2/2) DVD/CD LD DRIVE Q102 3-9 3-10 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DVP-NS15/NS51P/NS43P/NS53P/K56P 3-6. VIDEO (1) BLOCK DIAGRAM 13 15 5 7 9 11 33 24 28 30 12 25 34 29 27 BLANKING SIGNAL GENERATOR FUNCTION SIGNAL GENERATOR CN301 Y V C G R B VIDEO BUFFER SELECT SWITCH 19 16 15 11 8 7 DISCEXT RGBSEL WIDE XVMUTE EUROVY SW2 MUTE2 MUTE3 MUTE1 B IN G IN R IN C IN Y IN V IN V/Y OUT R/C OUT G OUT B OUT SW1 V/Y OUT BLANKING OUT R/C OUT G OUT FUNC. SW B OUT V/Y R/C G B H 2.0Vp-p MV-48 BOARD (DVP-NS15 ONLY) (SEE PAGE 4-43 to 4-44) SYSTEM CONTROL/ SIGNAL PROCESSOR (SEE PAGE 3-7 to 3-8) IC304 1.4Vp-p 1.4Vp-p 1.4Vp-p IC304 C/BAR PB (RGB MODE) 15 29 IC304 C/BAR PB (RGB MODE) 16 27 IC304 C/BAR PB (RGB MODE) 14 34 H 572 mVp-p (NTSC) 600 mVp-p (PAL) IC304 C/BAR PB (S-VIDEO MODE) 13 34 IC304 C/BAR PB (VIDEO MODE & RGB MODE) 12 25 H 2.0Vp-p IC304 C/BAR PB (S-VIDEO MODE) 11 25 D301 AUDIO/VIDEO OUTPUT 3-11 3-12 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DVP-NS15/NS51P/NS43P/NS53P/K56P 3-7. VIDEO (2) BLOCK DIAGRAM 3-13 3-14 S VIDEO OUT 32 29 27 31 23 25 21 8 11 13 1 16 3 5 Y C COMPONENT VIDEO OUT Y Cb Cr Sc/Cb/B SY/Y/G CVBS COMP-MUTE XVMUTE VIDEO IN VIDEO OUT MUTE1 Y OUT Y IN C IN C OUT MUTE2 Y IN Y OUT Cr/R Cb IN Cr IN Cb OUT Cr OUT VIDEO COMBO JACK VIDEO BUFFER SYSTEM CONTROL/ SIGNAL PROCESSOR (SEE PAGE 3-7 to 3-8) MV-47 BOARD (EXCEPT DVP-NS15) (SEE PAGE 4-31 to 4-32) IC304 J301 H 2.0Vp-p H IC304 C/BAR PB 16 31 IC304 C/BAR PB 12 29 H 2.0Vp-p IC304 C/BAR PB 11 27 IC304 C/BAR PB 13 IC304 C/BAR PB 14 IC304 C/BAR PB 15 25 2.0Vp-p H 1.4Vp-p 1.4Vp-p H H 23 21 572 mVp-p (NTSC) 600 mVp-p (PAL) MUTE Q306 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DVP-NS15/NS51P/NS43P/NS53P/K56P 3-8. AUDIO (1) BLOCK DIAGRAM L R R442 R443 R464 R467 R471 R415 R439 MV-47 BOARD (EXCEPT DVP-NS15) (SEE PAGE 4-33 to 4-34) SYSTEM CONTROL/ SIGNAL PROCESSOR (SEE PAGE 3-5 to 3-6) MIC XECHO AL AR SPDIF LINE OUT J301 OPTICAL COAXIAL DIGITAL OUTPUT DVP-NS51P/NS53P: AR,BR/K56P XA MUTE + – + – D IN 1 7 1 SYSTEM CONTROL/ SIGNAL PROCESSOR (SEE PAGE 3-5 to 3-6) MUTE DRIVER Q414 AUDIO AMPLIFIER IC402 AUDIO AMPLIFIER IC401 2 3 5 6 + – 1 7 2 3 5 6 4 5 6 4 5 6 CN404 XECHO SW+3.3V XMAMUTE KRMOD MUTE Q413 MUTE Q412 R463 DVP-K56P ONLY D402 D405 Voltage Detector IC406 DVP-K56P ONLY MUTE DRIVER Q406, Q409, Q410 MUTE DRIVER Q402, Q404, Q405 + – MUTE Q407 BUFFER Q411 MUTE Q408 DVP-K56P ONLY DVP-K56P ONLY DVP-K56P ONLY DVP-K56P ONLY 7 1 6 2 MIC AMP ECHO SET R532 R530 IC503 IN ECHO OUT IC504 MUTE DRIVER Q503, Q505 MIC DETE CT Q501, Q502 7 1 5 2 MIC AMP IC502 J501 MC-161 BOARD (DVP-K56P ONLY) (SEE PAGE 4-21 to 4-22) 2 9 MIC VR RV501 MIC IC405 EXCEPT DVP-K56P EXCEPT DVP-K56P 3-15 3-16 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DVP-NS15/NS51P/NS43P/NS53P/K56P 3-10. INTERFACE CONTROL (1) BLOCK DIAGRAM ND401 FLUORESCENT INDICATOR TUBE 3.3V REGULATOR IC407 PROG LED IR VCC VDD /RST VKK 50 69 71 77 12 38 4 11 EVER+3.3V EVER+3.3V EVER+3.3V SW-10V 1~2 40~41 SEG 1-20 DIG 1-7 AD1 AD2 XIN XOUT SYSRST /CS SI SO /SC /AMUTE /VMUTE BUSY PCONT POWER O/C SYSRST EVER+5V SW-10V SW+3.3V XIFCS SOO SIO SCO A-MUTE V-MUTE XIFBUSY PCONT POWER-SWITCH CN401 CN403 CN403 CN002 CN001 X401 8MHz 4 5 7 80 78 5 11 8 40 14 15 16 17 23 24 27 26 37 35 34 36 2 3 IF-144 BOARD (DVP-NS43P/NS53P/K56P) (SEE PAGE 4-13 to 4-14) IF-145 BOARD (DVP-NS51P ONLY) (SEE PAGE 4-17 to 4-18) IR RECEIVER IC406 3 1 RESET VFD DRIVER CIRCUIT IC408 2 1 DVP-NS43P/NS53P/K56P SW-468 BOARD (DVP-NS43P/NS53P ONLY) (SEE PAGE 4-51 to 4-52) SW-469 BOARD (DVP-K56P ONLY) (SEE PAGE 4-53 to 4-54) 13 11 2 4 7 6 9 14 10 5 12 16 15 5 6 4 3 7 8 6 4 2 5 1 7 3 2 4 5 1 S006 R031 R030 S001 S002 R029 S003 PREV PLAY OPEN/CLOSE N . NEXT > Z x R028 S004 S005 PROG STOP PROGRESSIVE D001 DVP-NS43P/NS53P/K56P ONLY DVP-NS43P/NS53P/K56P ONLY SW-475 BOARD (DVP-NS51P ONLY) (SEE PAGE 4-55 to 4-56) S001 x R028 S004 S005 PROG STOP PROGRESSIVE D001 2 4 6 8 5 9 3 PLAY N S006 OPEN/CLOSE Z IR RECEIVER IC001 2 1 SYSTEM CONTROL/SIGNAL PROCESSOR MV-47 (EXCEPT NS15) (SEE PAGE 3-5 to 3-6) MV-48 (NS15 ONLY) (SEE PAGE 3-7 to 3-8) ~ ~ ~ ~ IC404 IF MICON 3-19 3-20 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DVP-NS15/NS51P/NS43P/NS53P/K56P 3-11. INTERFACE CONTROL (2) BLOCK DIAGRAM 3.3V REGULATOR IC407 PLAY LED IR VDD /RST EVER+3.3V EVER+3.3V AD1 AD2 XIN XOUT SYSRST /CS SI SO /SC /AMUTE /VMUTE BUSY PCONT POWER O/C SYSRST EVER+5V SW+3.3V XIFCS SOO SIO SCO A-MUTE V-MUTE XIFBUSY PCONT POWER-SWITCH CN401 CN403 CN002 X401 8MHz 4 5 18 21 28 22 3 20 24 25 26 17 16 19 4 10 7 12 11 2 1 IF-143 BOARD (DVP-NS15 ONLY) (SEE PAGE 4-9 to 4-10) RESET IC408 2 1 13 11 2 4 7 6 9 14 10 5 12 16 8 6 4 2 7 3 5 SW-467 BOARD (DVP-NS15P ONLY) (SEE PAGE 4-49 to 4-50) S001 x S004 STOP D002 2 4 6 8 3 7 5 PLAY N S006 OPEN/CLOSE Z IR RECEIVER IC001 2 1 SYSTEM CONTROL/SIGNAL PROCESSOR MV-48 (DVP-NS15 ONLY) (SEE PAGE 3-7 to 3-8) R036 HOLD 27 IC404 IF MICON 3-21 3-22E w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DVP-NS15/NS51P/NS43P/NS53P/K56P 1 A B C D E F G H I 2 12 13 11 10 9 8 7 6 5 4 3 14 15 SECTION 4 PRINTED WIRING BOARDS AND SCHEMATIC DIAGRAMS 4-1 4-2 FRAME SCHEMATIC DIAGRAM 4-1. FRAME SCHEMATIC DIAGRAM M M SRV1872WW (EXCEPT DVP-NS53P:MX) SRV1873UC (DVP-NS53P:MX ONLY) SWITCHING REGULATOR MV-47 BOARD (EXCEPT DVP-NS15) MV-48 BOARD (DVP-NS15 ONLY) MS-203 BOARD BASE UNIT OPTICAL DEVICE (KHM-313CAA/C2RP) AC_IN (N) 2P AC_IN (L) 2 1 1-964-237-11 HARNESS PM-127 1 10P CN501 2 3 4 5 6 7 8 9 10 SW+8V MTR GND EVER+11V EVER+5V SW+3.3V SW+5V GND P-CONT POWER SW EVER-10V 1 10P CNXXX 2 3 4 5 6 7 8 9 10 SW+8V MTR GND EVER+11V EVER+5V SW+3.3V SW+5V GND P-CONT POWER SW EVER-10V 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 GND SYSRST 3.3V_MNT XIFCS XIFBUSY SIO SOO GND SCO V_MUTE SW+3.3V PCONT EVER+5V A_MUTE SW-10V POWER_SWITCH GND 5 4 3 2 1 OCSW1 / REV CKSW1 / FWD GND / CTL LDM- LDM+ 17P *CN404 GND SYSRST 3.3V_MNT XIFCS XIFBUSY SIO SOO GND SCO V_MUTE SW+3.3V PCONT EVER+5V A_MUTE SW-10V POWER_SWITCH GND 17P *CN106 5P CN001 1 2 3 4 5 OCSW1 / REV CKSW1 / FWD GND / CTL LDM- LDM+ 5P CN202 1-831-524-11 FFC (FMS-010) 1.0 pitch 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 GND (LD) 24P CN101 LD (650) N.C N.C PD LD (780) VR (650) VR (780) N.C VoE/e+g Vcc Vc GND (PDIC) VoF/f+n VoB/b VoA/a RF (LO:DVD, HI:CD) MSW VoD/d VoC/c TRK- TRK+ FCS+ FCS- 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 GND (LD) 24P CN101 LD (650) N.C N.C PD LD (780) VR (650) VR (780) N.C VoE/e+g Vcc Vc GND (PDIC) VoF/f+n VoB/b VoA/a RF (LO:DVD, HI:CD) MSW VoD/d VoC/c TRK- TRK+ FCS+ FCS- 1 2 3 4 5 6 1 2 3 4 5 6 6P CN201 SP- SP+ LIMIT (GND) LIMIT SL- SL+ 6P CNXXX SP- SP+ LIMIT (GND) LIMIT SL- SL+ FFC (FMO-009) 0.5 pitch 1-831-523-11 SPINDLE MOTOR LIMIT SWITCH SLIDER MOTOR FFC (FSW-002) 1-831-569-11 2 1 3 4 5 6 7 AD2 GND PLAY_LED O/C EVER+3.3V AD1 SW+3.3V 8 IR OUT 9 GND 9P CN403 8 9 7 6 5 4 3 AD2 Prog_LED GND O/C SW+3.3V AD1 EVER+3.3V 2 IR OUT 1 N.C 9P CN002 FFC (FSW-001) 1-831-522-11 6 7 5 4 3 2 1 AD2 O/C AD1 PROG_LED SW+3.3V GND GND 7P CN403 6 7 5 4 3 2 1 GND GND SW+3.3V PROG_LED AD1 AD2 O/C 7P CN001 7P CN051 HARNESS MD-111 1-963-599-11 IF-143 BOARD (DVP-NS15 ONLY) IF-145 BOARD (DVP-NS51P ONLY) IF-144 BOARD (DVP-NS43P/NS53P/K56P) SW-468 BOARD SW-469 BOARD SW-467 BOARD SW-475 BOARD (DVP-NS51P ONLY) (DVP-NS15 ONLY) (DVP-NS43P/NS53P ONLY) (DVP-K56P ONLY) 1 2 3 4 5 6 6P CN404 1 2 3 4 5 6 GND_AUDIO 6P CN501 AU-10V AU+11V XMIC MIC+ECHO XECHO GND_AUDIO AU-10V AU+11V XMIC MIC+ECHO XECHO 1-964-346-11 HARNESS MC-089 MC-161 BOARD (DVP-K56P ONLY) 5 4 3 2 1 PI TE FE GND RF 5P CN103 1 6P CN105 TO SERVO JIG 2 3 4 5 6 TXD RXD GND +3.3V V2REF0 RF MON w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DVP-NS15/NS51P/NS43P/NS53P/K56P For printed wiring boards: • : indicates a lead wire mounted on the component side. • : indicates a lead wire mounted on the printed side. • a : Through hole. • : Pattern from the side which enables seeing. (The other layers’ patterns are not indicated.) For schematic diagrams: • All capacitors are in µF unless otherwise noted. pF : µµF. 50V or less are not indicated except for electrolytics and tantalums. • All resistors are in ohms, 1/4W (Chip resistors : 1/10W) un-less otherwise specified. kΩ = 1000Ω, MΩ = 1000kΩ. • Caution when replacing chip parts. New parts must be attached after removal of chip. Be careful not to heat the minus side of tantalum capacitor, because it is damaged by the heat. • All variable and adjustable resistors have characteristic curve B, unless otherwise noted. • : non flammable resistor. • : fusible resistor. • : panel designation. • f : internal component. • : adjustment for repair. • Circled numbers refer to waveforms. • Voltages are dc between measurement point. • Readings are taken with a color-bar signal on DVD refer- ence disc and when playing CD reference disc. • Readings are taken with a digital multimeter (DC 10MΩ). • Voltage variations may be noted due to normal production tolerances. Caution: Pattern face side: Parts on the pattern face side seen from (Side A) the pattern face are indicated. Parts face side: Parts on the parts face side seen from (Side B) the parts face are indicated. 4-2. PRINTED WIRING BOARDS AND SCHEMATIC DIAGRAMS THIS NOTE IS COMMON FOR WIRING BOARDS AND SCHEMATIC DIAGRAMS. (In addition to this, the necessary note is printed in each block) WAVEFORMS MV-48 BOARD (DVP-NS15 ONLY) • Abbreviation AEP : AEP Model AR : Argentina Model AUS : Australia/New Zealand Model BR : Brazilian Model CH : Chinese Model E : Latin America Model EA : Saudi Arabia Model HK : Hong Kong Model IN : India Model IR : Iran Model KR : Korean Model ME2 : Middle East Model ME5 : IND,PAK,MAR Model MX : Mexican Model MY : Malaysian Model RUS : Russian Model SP : Singapore Model TW : Taiwan Model UK : UK Model VN : Vietnam Model When indicating parts by reference number, please include the board name. Note: The components identified by mark or dotted line with mark are critical for safety. Replace only with part number specified. 4-3 4-4 WAVEFORM MV-48 0.7Vp-p IC101 C/BAR PB (RGB MODE) 182 8 IC101 C/BAR PB (S-VIDEO MODE) 3 H 286 mVp-p (NTSC) 300 mVp-p (PAL) 181 IC101 C/BAR PB (S-VIDEO MODE) 4 1Vp-p H 179 IC101 C/BAR PB 5 1Vp-p H 175 0.7Vp-p IC101 C/BAR PB (RGB MODE) 7 181 IC101 9 1.9Vp-p 27MHz 228 3.3Vp-p 110MHz IC101 10 146 IC101 (CD PB) 1 200nsec (0.5Vp-p to 1.1Vp-p) 6 IC101 (DVD PB) 2 100nsec (0.65Vp-p to 1.48Vp-p) 6 H IC304 C/BAR PB (S-VIDEO MODE) 11 2.0Vp-p 25 H IC304 C/BAR PB (VIDEO MODE & RGB MODE) 12 2.0Vp-p 25 0.7Vp-p IC101 C/BAR PB (RGB MODE) 6 179 1.4Vp-p IC304 C/BAR PB (RGB MODE) 15 29 1.4Vp-p IC304 C/BAR PB (RGB MODE) 16 27 1.4Vp-p IC304 C/BAR PB (RGB MODE) 14 34 H IC304 C/BAR PB (S-VIDEO MODE) 13 572 mVp-p (NTSC) 600 mVp-p (PAL) 34 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DVP-NS15/NS51P/NS43P/NS53P/K56P 4-5 4-6 MV-47 BOARD (EXCEPT DVP-NS15) IC304 C/BAR PB 0.7Vp-p H 0.7Vp-p H 1Vp-p H 1Vp-p H 3.3Vp-p 110MHz H 2.0Vp-p H 2.0Vp-p H 2.0Vp-p 1.4Vp-p H 1.4Vp-p H 200nsec (0.5Vp-p to 1.1Vp-p) 100nsec (0.65Vp-p to 1.48Vp-p) H 572 mVp-p (NTSC) 600 mVp-p (PAL) 1.9Vp-p 27MHz H 286 mVp-p (NTSC) 300 mVp-p (PAL) IC101 C/BAR PB (COMPONENT OUT) 6 1Vp-p H IC101 (CD PB) 1 6 IC101 (DVD PB) 2 6 IC101 C/BAR PB (LINE OUT/S-VIDEO OUT) 3 181 IC101 C/BAR PB (LINE OUT/S-VIDEO OUT) 4 179 IC101 C/BAR PB (LINE OUT/S-VIDEO OUT) 5 175 179 IC101 (COMPONENT OUT) 7 181 IC101 (COMPONENT OUT) 8 182 IC101 9 228 IC101 10 146 IC304 C/BAR PB 11 27 12 29 IC304 C/BAR PB 13 25 IC304 14 23 IC304 15 21 IC304 C/BAR PB 16 31 WAVEFORM MV-47 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DVP-NS15/NS51P/NS43P/NS53P/K56P 3-9. AUDIO (2) BLOCK DIAGRAM L R R414 MV-48 BOARD (DVP-NS15 ONLY) (SEE PAGE 4-45 to 4-46) SYSTEM CONTROL/ SIGNAL PROCESSOR (SEE PAGE 3-7 to 3-8) AL AR SPDIF LINE OUT pin1 pin3 J401 COAXIAL XA MUTE + – + – CN301 1 7 SYSTEM CONTROL/ SIGNAL PROCESSOR (SEE PAGE 3-7 to 3-8) AUDIO AMPLIFIER IC401 2 6 SW+3.3V XMAMUTE MUTE Q413 MUTE Q412 D402 Voltage Detector IC402 MUTE DRIVER Q406, Q409, Q410 MUTE DRIVER Q402, Q404, Q405 MUTE Q407 BUFFER Q411 MUTE Q408 R437 3-17 3-18 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DVP-NS15/NS51P/NS43P/NS53P/K56P 4-8 IF-143 (INTERFACE) PRINTED WIRING BOARD IF-143 BOARD (SIDE A) (DVP-NS15 ONLY) • : Uses unleaded solder. There are a few cases that the part printed on this diagram isn’t mounted in this model. For printed wiring board 4-7 INTERFACE IF-143 A B C 1 2 3 A B C 1 2 3 IF-143 BOARD (SIDE B) (DVP-NS15 ONLY) (DVP-NS43P/NS53P) IF-144 Board (EXCEPT DVP-NS51P) (INTERFACE) SW-468 Board (EXCEPT DVP-NS51P) (SWITCH) MV-47 Board (CPU, Servo-DSP, AVDEC, DRIVE, VIDEO, AUDIO, POWER) Power Board (DVP-NS15) IF-143 Board (INTERFACE) SW-467 Board (SWITCH PWB) MV-48 Board (CPU, Servo-DSP, AVDEC, DRIVE, VIDEO D-EURO, AUDIO_EURO (D), POWER) Power Board (DVP-K56P) IF-144 Board (INTERFACE) MC-161 Board (MIC-ECHO) SW-469 Board (SWITCH BOARD) MV-47 Board (CPU, Servo-DSP, AVDEC, DRIVE, VIDEO, AUDIO, POWER) Power Board IF-143 BOARD SIDE B IC404 B-2 IC407 B-4 IC408 B-3 Q401 A-2 (DVP-NS51P) IF-145 Board (DVP-NS51P ONLY) (INTERFACE) SW-475 Board (DVP-NS51P ONLY) (SWITCH) MV-47 Board (CPU, Servo-DSP, AVDEC, DRIVE, VIDEO, AUDIO, POWER) Power Board w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DVP-NS15/NS51P/NS43P/NS53P/K56P 1 A B C D E F G H I J 2 12 13 11 10 9 8 7 6 5 4 3 14 15 For Schematic Diagram • Refer to page 4-7 for printed wiring board of IF-143 board. IF-143 BOARD (DVP-NS15 ONLY) INTERFACE -REF.NO.:1000 SERIES- XX MARK:NO MOUNT NO MARK:PB MODE MARKED:MOUNT TABLE TO CN002 SW-467 BOARD (DVP-NS15) (SEE PAGE 4-49 TO 4-50) TO CN106 MV-48 BOARD (DVP-NS15) (SEE PAGE 4-39 TO 4-40) 4-9 4-10 INTERFACE IF-143 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DVP-NS15/NS51P/NS43P/NS53P/K56P 4-12 IF-144 (INTERFACE) PRINTED WIRING BOARD 4-11 INTERFACE IF-144 IF-144 BOARD (SIDE A) (DVP-NS43P/NS53P/K56P ONLY) • : Uses unleaded solder. IF-144 BOARD (SIDE B) (DVP-NS43P/NS53P/K56P ONLY) There are a few cases that the part printed on this diagram isn’t mounted in this model. For printed wiring board (DVP-NS43P/NS53P) IF-144 Board (EXCEPT DVP-NS51P) (INTERFACE) SW-468 Board (EXCEPT DVP-NS51P) (SWITCH) MV-47 Board (CPU, Servo-DSP, AVDEC, DRIVE, VIDEO, AUDIO, POWER) Power Board (DVP-NS15) IF-143 Board (INTERFACE) SW-467 Board (SWITCH PWB) MV-48 Board (CPU, Servo-DSP, AVDEC, DRIVE, VIDEO D-EURO, AUDIO_EURO (D), POWER) Power Board (DVP-K56P) IF-144 Board (INTERFACE) MC-161 Board (MIC-ECHO) SW-469 Board (SWITCH BOARD) MV-47 Board (CPU, Servo-DSP, AVDEC, DRIVE, VIDEO, AUDIO, POWER) Power Board 1-866-100- 11 (11) A B C D 1 2 7 6 8 5 4 3 A B C D 1 2 7 6 8 5 4 3 IF-144 BOARD SIDE A IC406 A-5 SIDE B IC404 B-2 IC407 C-1 IC408 B-3 Q401 D-2 Q402 D-2 D401 D-2 D402 C-2 D403 D-2 D406 C-2 (DVP-NS51P) IF-145 Board (DVP-NS51P ONLY) (INTERFACE) SW-475 Board (DVP-NS51P ONLY) (SWITCH) MV-47 Board (CPU, Servo-DSP, AVDEC, DRIVE, VIDEO, AUDIO, POWER) Power Board w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DVP-NS15/NS51P/NS43P/NS53P/K56P 1 A B C D E F G H I J 2 12 13 11 10 9 8 7 6 5 4 3 14 15 For Schematic Diagram • Refer to page 4-11 for printed wiring board of IF-144 board. IF-144 BOARD (DVP-NS43P/NS53P/K56P ONLY) INTERFACE -REF.NO.:1000 SERIES- XX MARK:NO MOUNT NO MARK:PB MODE MARKED:MOUNT TABLE TO CN001 SW-468 BOARD (DVP-NS43P/NS53P) (SEE PAGE 4-51 TO 4-52) TO CN051 SW-469 BOARD (DVP-K56P) (SEE PAGE 4-53 TO 4-54) TO CN106 MV-47 BOARD (DVP-NS43P/NS53P/K56P) (SEE PAGE 4-29 TO 4-30) 4-13 4-14 INTERFACE IF-144 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DVP-NS15/NS51P/NS43P/NS53P/K56P (DVP-NS51P) 4-16 IF-145 (INTERFACE) PRINTED WIRING BOARD IF-145 BOARD (SIDE A) (DVP-NS51P ONLY) • : Uses unleaded solder. 4-15 INTERFACE IF-145 There are a few cases that the part printed on this diagram isn’t mounted in this model. For printed wiring board (DVP-NS43P/NS53P) IF-144 Board (EXCEPT DVP-NS51P) (INTERFACE) SW-468 Board (EXCEPT DVP-NS51P) (SWITCH) MV-47 Board (CPU, Servo-DSP, AVDEC, DRIVE, VIDEO, AUDIO, POWER) Power Board (DVP-NS15) IF-143 Board (INTERFACE) SW-467 Board (SWITCH PWB) MV-48 Board (CPU, Servo-DSP, AVDEC, DRIVE, VIDEO D-EURO, AUDIO_EURO (D), POWER) Power Board (DVP-K56P) IF-144 Board (INTERFACE) MC-161 Board (MIC-ECHO) SW-469 Board (SWITCH BOARD) MV-47 Board (CPU, Servo-DSP, AVDEC, DRIVE, VIDEO, AUDIO, POWER) Power Board IF-145 BOARD (SIDE B) (DVP-NS51P ONLY) 1-868-102- 11 (11) A B C D 1 2 7 6 8 5 4 3 A B C D 1 2 7 6 8 5 4 3 IF-145 BOARD SIDE B IC404 B-2 IC407 C-1 IC408 B-3 Q401 D-2 Q402 D-2 D402 C-2 D403 D-2 D406 D-2 IF-145 Board (DVP-NS51P ONLY) (INTERFACE) SW-475 Board (DVP-NS51P ONLY) (SWITCH) MV-47 Board (CPU, Servo-DSP, AVDEC, DRIVE, VIDEO, AUDIO, POWER) Power Board w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DVP-NS15/NS51P/NS43P/NS53P/K56P 1 A B C D E F G H I J 2 12 13 11 10 9 8 7 6 5 4 3 14 15 For Schematic Diagram • Refer to page 4-15 for printed wiring board of IF-145 board. IF-145 BOARD (DVP-NS51P ONLY) INTERFACE -REF.NO.:1000 SERIES- XX MARK:NO MOUNT NO MARK:PB MODE MARKED:MOUNT TABLE TO CN106 MV-47 BOARD (DVP-NS51P ONLY) (SEE PAGE 4-27 TO 4-28) TO CN002 SW-475 BOARD (DVP-NS51P ONLY) (SEE PAGE 4-55 TO 4-56) 4-17 4-18 INTERFACE IF-145 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DVP-NS15/NS51P/NS43P/NS53P/K56P 4-20 • : Uses unleaded solder. 4-19 MIC-ECHO MC-161 MC-161 (MIC-ECHO) PRINTED WIRING BOARD There are a few cases that the part printed on this diagram isn’t mounted in this model. For printed wiring board (DVP-NS43P/NS53P) IF-144 Board (EXCEPT DVP-NS51P) (INTERFACE) SW-468 Board (EXCEPT DVP-NS51P) (SWITCH) MV-47 Board (CPU, Servo-DSP, AVDEC, DRIVE, VIDEO, AUDIO, POWER) Power Board (DVP-NS15) IF-143 Board (INTERFACE) SW-467 Board (SWITCH PWB) MV-48 Board (CPU, Servo-DSP, AVDEC, DRIVE, VIDEO D-EURO, AUDIO_EURO (D), POWER) Power Board (DVP-K56P) IF-144 Board (INTERFACE) MC-161 Board (MIC-ECHO) SW-469 Board (SWITCH BOARD) MV-47 Board (CPU, Servo-DSP, AVDEC, DRIVE, VIDEO, AUDIO, POWER) Power Board A B C D E 1 2 A B C D 1 2 MC-161 BOARD (DVP-K56P ONLY) SIDE A MC-161 BOARD (DVP-K56P ONLY) SIDE B MC-161 BOARD SIDE B IC501 A-2 IC502 C-2 IC503 B-2 IC504 B-1 Q501 D-1 Q502 D-1 Q503 B-2 Q504 B-1 Q505 B-1 D501 D-1 D502 D-1 D503 B-1 (DVP-NS51P) IF-145 Board (DVP-NS51P ONLY) (INTERFACE) SW-475 Board (DVP-NS51P ONLY) (SWITCH) MV-47 Board (CPU, Servo-DSP, AVDEC, DRIVE, VIDEO, AUDIO, POWER) Power Board w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DVP-NS15/NS51P/NS43P/NS53P/K56P 1 A B C D E F G H I J 2 12 13 11 10 9 8 7 6 5 4 3 14 15 For Schematic Diagram • Refer to page 4-19 for printed wiring board of MC-161 board. MC-161 BOARD (DVP-K56P ONLY) MIC-ECHO -REF.NO.:1000 SERIES- XX MARK:NO MOUNT NO MARK:PB MODE MARKED:MOUNT TABLE TO CN404 MV-47 BOARD (SEE PAGE 4-33 TO 4-34) 4-21 4-22 MIC-ECHO MC-161 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DVP-NS15/NS51P/NS43P/NS53P/K56P 4-24 • : Uses unleaded solder. 4-23 LOADING MOTOR MS-203 For Schematic Diagram • Refer to page 4-23 for printed wiring board of MS-203 board. MS-203 BOARD LOADING MOTOR -REF.NO.:1000 SERIES- XX MARK:NO MOUNT NO MARK:REC/PB MODE MS-203 (LOADING MOTOR) PRINTED WIRING BOARD MS-203 BOARD There are a few cases that the part printed on this diagram isn’t mounted in this model. For printed wiring board (DVP-NS43P/NS53P) IF-144 Board (EXCEPT DVP-NS51P) (INTERFACE) SW-468 Board (EXCEPT DVP-NS51P) (SWITCH) MV-47 Board (CPU, Servo-DSP, AVDEC, DRIVE, VIDEO, AUDIO, POWER) Power Board (DVP-NS15) IF-143 Board (INTERFACE) SW-467 Board (SWITCH PWB) MV-48 Board (CPU, Servo-DSP, AVDEC, DRIVE, VIDEO D-EURO, AUDIO_EURO (D), POWER) Power Board (DVP-K56P) IF-144 Board (INTERFACE) MC-161 Board (MIC-ECHO) SW-469 Board (SWITCH BOARD) MV-47 Board (CPU, Servo-DSP, AVDEC, DRIVE, VIDEO, AUDIO, POWER) Power Board 1 A B C D 2 7 6 5 4 3 M001 5P CN001 1 2 3 4 5 JL001 JL002 JL003 JL004 JL005 TO MV-47 BOARD (2/5) CN202 (SEE PAGE 4-29 TO 4-30) LOADING MOTOR C001 XX LDM+ LDM- OCSW1 CKSW1 GND/CTL S001 DETECT CHUCK/TRAY 1 3 2 CN001 S001 (CHUCK/TRAY DETECT) C001 S001 1-861-327- 12 21 5 4 1 2 1 2 3 M001 (LOADING MOTOR) + - M (DVP-NS51P) IF-145 Board (DVP-NS51P ONLY) (INTERFACE) SW-475 Board (DVP-NS51P ONLY) (SWITCH) MV-47 Board (CPU, Servo-DSP, AVDEC, DRIVE, VIDEO, AUDIO, POWER) Power Board w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DVP-NS15/NS51P/NS43P/NS53P/K56P CPU, Servo-DSP, AVDEC, DRIVE, VIDEO, AUDIO, POWER MV-47 MV-47 (CPU, Servo-DSP, AVDEC, DRIVE, VIDEO, AUDIO, POWER) PRINTED WIRING BOARD • : Uses unleaded solder. MV-47 BOARD (EXCEPT DVP-NS15) SIDE A MV-47 BOARD (EXCEPT DVP-NS15) SIDE B 4-26 There are a few cases that the part printed on this diagram isn’t mounted in this model. For printed wiring board (DVP-NS43P/NS53P) IF-144 Board (EXCEPT DVP-NS51P) (INTERFACE) SW-468 Board (EXCEPT DVP-NS51P) (SWITCH) MV-47 Board (CPU, Servo-DSP, AVDEC, DRIVE, VIDEO, AUDIO, POWER) Power Board (DVP-NS15) IF-143 Board (INTERFACE) SW-467 Board (SWITCH PWB) MV-48 Board (CPU, Servo-DSP, AVDEC, DRIVE, VIDEO D-EURO, AUDIO_EURO (D), POWER) Power Board (DVP-K56P) IF-144 Board (INTERFACE) MC-161 Board (MIC-ECHO) SW-469 Board (SWITCH BOARD) MV-47 Board (CPU, Servo-DSP, AVDEC, DRIVE, VIDEO, AUDIO, POWER) Power Board A B C D E F G 1 2 5 4 3 A B C D E F 1 2 5 4 3 MV-47 BOARD SIDE A IC102 B-3 IC103 B-4 IC104 C-5 IC105 D-5 IC108 A-4 IC110 D-2 IC201 B-2 IC401 E-4 IC402 E-4 IC405 G-5 D301 F-2 D302 F-1 D303 F-1 D310 E-3 D402 E-4 D405 E-4 Q101 C-2 Q102 C-2 Q304 F-2 Q305 F-2 Q306 E-3 Q401 E-3 Q402 E-5 Q403 E-3 Q404 E-5 Q405 F-5 Q406 E-5 Q409 E-5 Q410 F-5 Q412 E-4 Q413 E-4 Q414 F-3 Q417 F-4 Q501 E-1 Q502 E-1 SIDE B IC107 D-3 IC303 F-5 IC304 F-4 IC403 E-3 D308 F-4 D309 F-4 D401 E-1 D404 E-3 Q407 F-3 Q408 F-2 Q411 F-1 Q416 E-3 (DVP-NS51P) IF-145 Board (DVP-NS51P ONLY) (INTERFACE) SW-475 Board (DVP-NS51P ONLY) (SWITCH) MV-47 Board (CPU, Servo-DSP, AVDEC, DRIVE, VIDEO, AUDIO, POWER) Power Board w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DVP-NS15/NS51P/NS43P/NS53P/K56P 1 A B C D E F G H I J 2 12 13 11 10 9 8 7 6 5 4 3 14 15 For Schematic Diagram • Refer to page 4-25 for printed wiring board of MV-47 board. • Refer to page 4-5 for waveform MV-47 BOARD (1/5) (EXCEPT DVP-NS15) CPU, Servo-DSP, AVDEC -REF.NO.:1000 SERIES- XX MARK:NO MOUNT NO MARK:REC/PB MODE 4-27 4-28 CPU, Servo-DSP, AVDEC MV-47 (1/5) TO IF144 BOARD (DVP-NS43P/NS53P/K56P) TO IF145 BOARD (DVP-NS51P ONLY) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DVP-NS15/NS51P/NS43P/NS53P/K56P 1 A B C D E F G H I J 2 12 13 11 10 9 8 7 6 5 4 3 14 15 For Schematic Diagram • Refer to page 4-25 for printed wiring board of MV-47 board. • Refer to page 4-5 for waveform MV-47 BOARD (2/5) (EXCEPT DVP-NS15) DRIVE -REF.NO.:1000 SERIES- XX MARK:NO MOUNT NO MARK:REC/PB MODE 4-29 4-30 DRIVE MV-50 (2/5) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DVP-NS15/NS51P/NS43P/NS53P/K56P 1 A B C D E F G H I J 2 12 13 11 10 9 8 7 6 5 4 3 14 15 For Schematic Diagram • Refer to page 4-25 for printed wiring board of MV-47 board. • Refer to page 4-5 for waveform MV-47 BOARD (3/5) (EXCEPT DVP-NS15) VIDEO -REF.NO.:1000 SERIES- XX MARK:NO MOUNT NO MARK:REC/PB MODE 4-31 4-32 VIDEO MV-47 (3/5) 18 14 13 15 16 17 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DVP-NS15/NS51P/NS43P/NS53P/K56P 1 A B C D E F G H I J 2 12 13 11 10 9 8 7 6 5 4 3 14 15 4-33 4-34 AUDIO MV-47 (4/5) For Schematic Diagram • Refer to page 4-25 for printed wiring board of MV-47 board. • Refer to page 4-5 for waveform MV-47 BOARD (4/5) (EXCEPT DVP-NS15) AUDIO -REF.NO.:1000 SERIES- XX MARK:NO MOUNT NO MARK:REC/PB MODE w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DVP-NS15/NS51P/NS43P/NS53P/K56P 1 A B C D E F G H I J 2 12 13 11 10 9 8 7 6 5 4 3 14 15 The components identified by mark or dotted line with mark are critical for safety. Replace only with part number specified. 4-35 4-36 POWER MV-47 (5/5) For Schematic Diagram • Refer to page 4-25 for printed wiring board of MV-47 board. • Refer to page 4-5 for waveform MV-47 BOARD (5/5) (EXCEPT DVP-NS15) POWER -REF.NO.:1000 SERIES- XX MARK:NO MOUNT NO MARK:REC/PB MODE XX w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DVP-NS15/NS51P/NS43P/NS53P/K56P CPU, Servo-DSP, AVDEC, DRIVE, VIDEO D-EURO, AUDIO_EURO (D), POWER MV-48 MV-48 (CPU, Servo-DSP, AVDEC, DRIVE, VIDEO D-EURO, AUDIO_EURO (D), POWER) PRINTED WIRING BOARD • : Uses unleaded solder. MV-48 BOARD (DVP-NS15 ONLY) SIDE A MV-48 BOARD (DVP-NS15 ONLY) SIDE B 4-38 A B C D E F G 1 2 5 4 3 A B C D E F 1 2 5 4 3 There are a few cases that the part printed on this diagram isn’t mounted in this model. For printed wiring board (DVP-NS43P/NS53P) IF-144 Board (EXCEPT DVP-NS51P) (INTERFACE) SW-468 Board (EXCEPT DVP-NS51P) (SWITCH) MV-47 Board (CPU, Servo-DSP, AVDEC, DRIVE, VIDEO, AUDIO, POWER) Power Board (DVP-NS15) IF-143 Board (INTERFACE) SW-467 Board (SWITCH PWB) MV-48 Board (CPU, Servo-DSP, AVDEC, DRIVE, VIDEO D-EURO, AUDIO_EURO (D), POWER) Power Board (DVP-K56P) IF-144 Board (INTERFACE) MC-161 Board (MIC-ECHO) SW-469 Board (SWITCH BOARD) MV-47 Board (CPU, Servo-DSP, AVDEC, DRIVE, VIDEO, AUDIO, POWER) Power Board (DVP-NS51P) IF-145 Board (DVP-NS51P ONLY) (INTERFACE) SW-475 Board (DVP-NS51P ONLY) (SWITCH) MV-47 Board (CPU, Servo-DSP, AVDEC, DRIVE, VIDEO, AUDIO, POWER) Power Board MV-48 BOARD SIDE A IC101 C-3 IC102 B-3 IC103 B-4 IC104 C-5 IC105 D-5 IC106 D-5 IC108 A-4 IC110 D-2 IC201 B-2 IC401 E-4 IC402 E-5 D301 F-3 D302 F-3 D303 F-2 D304 F-3 D305 F-2 D306 F-2 D307 F-1 D308 F-1 D309 F-2 D310 F-2 D402 E-5 Q101 C-2 Q102 C-2 Q103 C-2 Q301 F-3 Q302 F-3 Q303 F-3 Q304 F-3 Q305 F-3 Q306 F-3 Q307 F-1 Q371 E-1 Q372 E-1 Q373 E-1 Q374 E-1 Q401 E-3 Q402 E-5 Q403 E-3 Q404 E-5 Q405 F-5 Q406 E-5 Q407 F-1 Q408 F-1 Q409 E-5 Q410 F-5 Q412 E-4 Q413 E-4 Q501 E-1 Q502 D-1 SIDE B IC107 D-3 IC303 F-5 IC304 F-3 IC403 E-2 D401 E-1 D404 E-3 Q411 F-1 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DVP-NS15/NS51P/NS43P/NS53P/K56P 1 A B C D E F G H I J 2 12 13 11 10 9 8 7 6 5 4 3 14 15 For Schematic Diagram • Refer to page 4-37 for printed wiring board of MV-48 board. • Refer to page 4-4 for waveform MV-48 BOARD (1/5) (DVP-NS15 ONLY) CPU, Servo-DSP, AVDEC -REF.NO.:1000 SERIES- XX MARK:NO MOUNT NO MARK:REC/PB MODE 4-39 4-40 CPU, Servo-DSP, AVDEC MV-48 (1/5) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DVP-NS15/NS51P/NS43P/NS53P/K56P 1 A B C D E F G H I J 2 12 13 11 10 9 8 7 6 5 4 3 14 15 For Schematic Diagram • Refer to page 4-37 for printed wiring board of MV-48 board. • Refer to page 4-4 for waveform MV-48 BOARD (2/5) (DVP-NS15 ONLY) DRIVE -REF.NO.:1000 SERIES- XX MARK:NO MOUNT NO MARK:REC/PB MODE 4-41 4-42 DRIVE MV-48 (2/5) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DVP-NS15/NS51P/NS43P/NS53P/K56P 1 A B C D E F G H I J 2 12 13 11 10 9 8 7 6 5 4 3 14 15 For Schematic Diagram • Refer to page 4-37 for printed wiring board of MV-48 board. • Refer to page 4-4 for waveform MV-48 BOARD (3/5) (DVP-NS15 ONLY) VIDEO D-EURO -REF.NO.:1000 SERIES- XX MARK:NO MOUNT NO MARK:REC/PB MODE 4-43 4-44 VIDEO D-EURO MV-48 (3/5) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DVP-NS15/NS51P/NS43P/NS53P/K56P 1 A B C D E F G H I J 2 12 13 11 10 9 8 7 6 5 4 3 14 15 4-45 4-46 AUDIO_EURO (D) MV-48 (4/5) For Schematic Diagram • Refer to page 4-37 for printed wiring board of MV-48 board. • Refer to page 4-4 for waveform MV-48 BOARD (4/5) (DVP-NS15 ONLY) AUDIO_EURO (D) -REF.NO.:1000 SERIES- XX MARK:NO MOUNT NO MARK:REC/PB MODE w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DVP-NS15/NS51P/NS43P/NS53P/K56P 1 A B C D E F G H I J 2 12 13 11 10 9 8 7 6 5 4 3 14 15 The components identified by mark or dotted line with mark are critical for safety. Replace only with part number specified. 4-47 4-48 POWER MV-48 (5/5) For Schematic Diagram • Refer to page 4-37 for printed wiring board of MV-48 board. • Refer to page 4-4 for waveform MV-48 BOARD (5/5) (DVP-NS15 ONLY) -REF.NO.:1000 SERIES- XX MARK:NO MOUNT NO MARK:REC/PB MODE w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DVP-NS15/NS51P/NS43P/NS53P/K56P 4-50 SW-467 (SWITCH PWB) PRINTED WIRING BOARD • : Uses unleaded solder. 4-49 SWITCH PWB SW-467 For Schematic Diagram • Refer to page 4-49 for printed wiring board of SW-467 board. SW-467 BOARD (DVP-NS15 ONLY) SWITCH PWB -REF.NO.:1000 SERIES- XX MARK:NO MOUNT NO MARK:REC/PB MODE There are a few cases that the part printed on this diagram isn’t mounted in this model. For printed wiring board There are a few cases that the part printed on this diagram isn’t mounted in this model. For printed wiring board (DVP-NS43P/NS53P) IF-144 Board (EXCEPT DVP-NS51P) (INTERFACE) SW-468 Board (EXCEPT DVP-NS51P) (SWITCH) MV-47 Board (CPU, Servo-DSP, AVDEC, DRIVE, VIDEO, AUDIO, POWER) Power Board (DVP-NS15) IF-143 Board (INTERFACE) SW-467 Board (SWITCH PWB) MV-48 Board (CPU, Servo-DSP, AVDEC, DRIVE, VIDEO D-EURO, AUDIO_EURO (D), POWER) Power Board 1 A B C D E F 2 8 7 6 5 4 3 TO CN403 IF143 BOARD (DVP-NS15 ONLY) (SEE PAGE 4-9 TO 4-10) SW-467 BOARD (DVP-NS15 ONLY) SIDE A SW-467 BOARD (DVP-NS15 ONLY) SIDE B A 1 2 3 4 A 1 2 3 4 (DVP-K56P) IF-144 Board (INTERFACE) MC-161 Board (MIC-ECHO) SW-469 Board (SWITCH BOARD) MV-47 Board (CPU, Servo-DSP, AVDEC, DRIVE, VIDEO, AUDIO, POWER) Power Board SW-467 BOARD SIDE A IC001 A-4 D002 A-2 (DVP-NS51P) IF-145 Board (DVP-NS51P ONLY) (INTERFACE) SW-475 Board (DVP-NS51P ONLY) (SWITCH) MV-47 Board (CPU, Servo-DSP, AVDEC, DRIVE, VIDEO, AUDIO, POWER) Power Board w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DVP-NS15/NS51P/NS43P/NS53P/K56P 4-52 SW-468 (SWITCH) PRINTED WIRING BOARD • : Uses unleaded solder. 4-51 SWITCH SW-468 1 A B C D 2 7 6 5 4 3 For Schematic Diagram • Refer to page 4-51 for printed wiring board of SW-468 board. SW-468 BOARD (DVP-NS43P/NS53P ONL Y) SWITCH -REF.NO.:1000 SERIES- XX MARK:NO MOUNT NO MARK:REC/PB MODE There are a few cases that the part printed on this diagram isn’t mounted in this model. For printed wiring board (DVP-NS43P/NS53P) IF-144 Board (EXCEPT DVP-NS51P) (INTERFACE) SW-468 Board (EXCEPT DVP-NS51P) (SWITCH) MV-47 Board (CPU, Servo-DSP, AVDEC, DRIVE, VIDEO, AUDIO, POWER) Power Board (DVP-NS15) IF-143 Board (INTERFACE) SW-467 Board (SWITCH PWB) MV-48 Board (CPU, Servo-DSP, AVDEC, DRIVE, VIDEO D-EURO, AUDIO_EURO (D), POWER) Power Board SW-468 BOARD (DVP-NS43P/NS53P/56P ONL Y) SIDE A SW -468 BO ARD (D VP-NS43P/NS53P ONLY)SIDE B A 1 2 3 A 1 2 3 TO CN403 IF144 BOARD (DVP-NS43P/NS53P) (SEE PAGE 4-13 TO 4-14) (DVP-K56P) IF-144 Board (INTERFACE) MC-161 Board (MIC-ECHO) SW-469 Board (SWITCH BOARD) MV-47 Board (CPU, Servo-DSP, AVDEC, DRIVE, VIDEO, AUDIO, POWER) Power Board (DVP-NS51P) IF-145 Board (DVP-NS51P ONLY) (INTERFACE) SW-475 Board (DVP-NS51P ONLY) (SWITCH) MV-47 Board (CPU, Servo-DSP, AVDEC, DRIVE, VIDEO, AUDIO, POWER) Power Board w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DVP-NS15/NS51P/NS43P/NS53P/K56P 4-54 SW-469 (SWITCH BOARD) PRINTED WIRING BOARD • : Uses unleaded solder. 4-53 SWITCH BOARD SW-469 There are a few cases that the part printed on this diagram isn’t mounted in this model. For printed wiring board SW-469 BOARD (DVP-K56P ONLY) SIDE A SW-469 BOARD (DVP-K56P ONLY) SIDE B (DVP-NS43P/NS53P) IF-144 Board (EXCEPT DVP-NS51P) (INTERFACE) SW-468 Board (EXCEPT DVP-NS51P) (SWITCH) MV-47 Board (CPU, Servo-DSP, AVDEC, DRIVE, VIDEO, AUDIO, POWER) Power Board (DVP-NS15) IF-143 Board (INTERFACE) SW-467 Board (SWITCH PWB) MV-48 Board (CPU, Servo-DSP, AVDEC, DRIVE, VIDEO D-EURO, AUDIO_EURO (D), POWER) Power Board A 1 2 A 1 2 1 A B C D 2 7 6 5 4 3 For Schematic Diagram • Refer to page 4-53 for printed wiring board of SW-469 board. SW-469 BOARD (DVP-K56P ONLY) SWITCH BOARD -REF.NO.:1000 SERIES- XX MARK:NO MOUNT NO MARK:REC/PB MODE TO CN403 IF144 BOARD (DVP-K56P ONLY) (SEE PAGE 4-13 TO 4-14) (DVP-K56P) IF-144 Board (INTERFACE) MC-161 Board (MIC-ECHO) SW-469 Board (SWITCH BOARD) MV-47 Board (CPU, Servo-DSP, AVDEC, DRIVE, VIDEO, AUDIO, POWER) Power Board SW-469 BOARD SIDE A D051 A-1 (DVP-NS51P) IF-145 Board (DVP-NS51P ONLY) (INTERFACE) SW-475 Board (DVP-NS51P ONLY) (SWITCH) MV-47 Board (CPU, Servo-DSP, AVDEC, DRIVE, VIDEO, AUDIO, POWER) Power Board w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DVP-NS15/NS51P/NS43P/NS53P/K56P 4-56 SW-475 (SWITCH) PRINTED WIRING BOARD • : Uses unleaded solder. 4-55 SWITCH SW-475 For Schematic Diagram • Refer to page 4-55 for printed wiring board of SW-475 board. SW-475 BOARD (DVP-NS51P ONLY) SWITCH -REF.NO.:1000 SERIES- XX MARK:NO MOUNT NO MARK:REC/PB MODE 1 A B C D E F 2 7 6 5 4 3 There are a few cases that the part printed on this diagram isn’t mounted in this model. For printed wiring board (DVP-NS43P/NS53P) IF-144 Board (EXCEPT DVP-NS51P) (INTERFACE) SW-468 Board (EXCEPT DVP-NS51P) (SWITCH) MV-47 Board (CPU, Servo-DSP, AVDEC, DRIVE, VIDEO, AUDIO, POWER) Power Board (DVP-NS15) IF-143 Board (INTERFACE) SW-467 Board (SWITCH PWB) MV-48 Board (CPU, Servo-DSP, AVDEC, DRIVE, VIDEO D-EURO, AUDIO_EURO (D), POWER) Power Board SW-475 BOARD (DVP-51P ONLY) SIDE A SW-475 BOARD (DVP-51P ONLY) SIDE B A 1 2 3 4 A 1 2 3 4 TO CN403 IF145 BOARD (DVP-NS51P ONLY) (SEE PAGE 4-17 TO 4-18) (DVP-K56P) IF-144 Board (INTERFACE) MC-161 Board (MIC-ECHO) SW-469 Board (SWITCH BOARD) MV-47 Board (CPU, Servo-DSP, AVDEC, DRIVE, VIDEO, AUDIO, POWER) Power Board SW-475 BOARD SIDE A IC001 A-1 (DVP-NS51P) IF-145 Board (DVP-NS51P ONLY) (INTERFACE) SW-475 Board (DVP-NS51P ONLY) (SWITCH) MV-47 Board (CPU, Servo-DSP, AVDEC, DRIVE, VIDEO, AUDIO, POWER) Power Board w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DVP-NS15/NS51P/NS43P/NS53P/K56P POWER BLOCK (SRV1872WW) PRINTED WIRING BOARD POWER BOARD (SRV1872WW) (SIDE A) (EXCEPT DVP-NS53P:MX) POWER BOARD (SRV1872WW) (SIDE B) (EXCEPT DVP-NS53P:MX) • : Uses unleaded solder. B A 1 2 7 6 5 4 3 B A 1 2 7 6 5 4 3 4-58 4-57 POWER BOARD POWER BLOCK (SRV1872WW) POWER BOARD (SRV1872WW) SIDE A IC101 B-4 Q211 A-6 D105 C-4 D106 B-4 D107 A-3 D108 A-4 D211 A-5 D212 C-5 D311 B-5 D312 B-6 D313 B-5 D315 B-6 D317 A-6 D318 A-7 D319 B-7 D411 B-5 D511 C-5 SIDE B IC611 A-3 D101 C-6 Q311 A-1 Q611 B-2 Q712 A-1 There are a few cases that the part printed on this diagram isn’t mounted in this model. For printed wiring board (DVP-NS43P/NS53P) IF-144 Board (EXCEPT DVP-NS51P) (INTERFACE) SW-468 Board (EXCEPT DVP-NS51P) (SWITCH) MV-47 Board (CPU, Servo-DSP, AVDEC, DRIVE, VIDEO, AUDIO, POWER) Power Board (DVP-NS15) IF-143 Board (INTERFACE) SW-467 Board (SWITCH PWB) MV-48 Board (CPU, Servo-DSP, AVDEC, DRIVE, VIDEO D-EURO, AUDIO_EURO (D), POWER) Power Board (DVP-K56P) IF-144 Board (INTERFACE) MC-161 Board (MIC-ECHO) SW-469 Board (SWITCH BOARD) MV-47 Board (CPU, Servo-DSP, AVDEC, DRIVE, VIDEO, AUDIO, POWER) Power Board (DVP-NS51P) IF-145 Board (DVP-NS51P ONLY) (INTERFACE) SW-475 Board (DVP-NS51P ONLY) (SWITCH) MV-47 Board (CPU, Servo-DSP, AVDEC, DRIVE, VIDEO, AUDIO, POWER) Power Board w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DVP-NS15/NS51P/NS43P/NS53P/K56P 1 A B C D E F G H I J 2 12 13 11 10 9 8 7 6 5 4 3 14 15 10 9 8 7 6 5 4 3 2 1 EVER-10V POWER SW P-CONT GND SW+5V SW+3.3V EVER+5V EVER+11V MTR GND SW+8V CN201 TO CN501 POWER MV-47 BOARD (EXCEPT AEP) (SEE PAGE 4-35 TO 4-36) MV-48 BOARD (AEP ONLY) (SEE PAGE 4-47 TO 4-48) The components identified by mark or dotted line with mark are critical for safety. Replace only with part number specified. 4-59 4-60 For Schematic Diagram • Refer to page 4-57 for printed wiring board of Power board. POWER BOARD POWER SUPPLY (SRV1872WW) (EXCEPT DVP-NS53P:MX) -REF.NO.:1000 SERIES- XX MARK:NO MOUNT NO MARK:PB MODE MARKED:MOUNT TABLE POWER BOARD POWER BLOCK (SRV1872WW) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DVP-NS15/NS51P/NS43P/NS53P/K56P POWER BLOCK (SRV1873UC) PRINTED WIRING BOARD POWER BOARD (SRV1873UC) (SIDE A) (DVP-NS53P: MX ONLY) POWER BOARD (SRV1873UC) (SIDE B) (DVP-NS53P: MX ONLY) • : Uses unleaded solder. 4-62 4-61 POWER BOARD POWER BLOCK (SRV1873UC) B A 1 2 7 6 5 4 3 B A 1 2 7 6 5 4 3 POWER BOARD (SRV1873UC) SIDE A IC101 B-4 Q211 A-6 D106 B-4 D107 A-3 D108 A-4 D211 A-5 D212 C-5 D311 B-5 D312 B-6 D313 B-5 D315 B-6 D317 B-6 D318 A-7 D319 B-7 D411 B-5 D511 C-5 SIDE B IC611 A-3 Q311 A-1 Q611 B-2 Q712 A-1 D101 C-6 There are a few cases that the part printed on this diagram isn’t mounted in this model. For printed wiring board (DVP-NS43P/NS53P) IF-144 Board (EXCEPT DVP-NS51P) (INTERFACE) SW-468 Board (EXCEPT DVP-NS51P) (SWITCH) MV-47 Board (CPU, Servo-DSP, AVDEC, DRIVE, VIDEO, AUDIO, POWER) Power Board (DVP-NS15) IF-143 Board (INTERFACE) SW-467 Board (SWITCH PWB) MV-48 Board (CPU, Servo-DSP, AVDEC, DRIVE, VIDEO D-EURO, AUDIO_EURO (D), POWER) Power Board (DVP-K56P) IF-144 Board (INTERFACE) MC-161 Board (MIC-ECHO) SW-469 Board (SWITCH BOARD) MV-47 Board (CPU, Servo-DSP, AVDEC, DRIVE, VIDEO, AUDIO, POWER) Power Board (DVP-NS51P) IF-145 Board (DVP-NS51P ONLY) (INTERFACE) SW-475 Board (DVP-NS51P ONLY) (SWITCH) MV-47 Board (CPU, Servo-DSP, AVDEC, DRIVE, VIDEO, AUDIO, POWER) Power Board w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DVP-NS15/NS51P/NS43P/NS53P/K56P 1 A B C D E F G H I J 2 12 13 11 10 9 8 7 6 5 4 3 14 15 10 9 8 7 6 5 4 3 2 1 EVER-10V POWER SW P-CONT GND SW+5V SW+3.3V EVER+5V EVER+11V MTR GND SW+8V CN201 TO CN501 POWER MV-47 BOARD (SEE PAGE 4-35 TO 4-36) The components identified by mark or dotted line with mark are critical for safety. Replace only with part number specified. For Schematic Diagram • Refer to page 4-61 for printed wiring board of Power board. POWER BOARD POWER SUPPLY (SRV1873UC) (DVP-NS53P: MX ONLY) -REF.NO.:1000 SERIES- XX MARK:NO MOUNT NO MARK:PB MODE MARKED:MOUNT TABLE 4-63 4-64E POWER BOARD POWER BLOCK (SRV1873UC) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 5-1 DVP-NS15/NS51P/NS43P/NS53P/K56P SECTION 5 IC PIN FUNCTION DESCRIPTION Pin No. Pin name Type Function 1 AGND Ground Ground pin for analog circuitry 2 DVDA Analog Input AC coupled input path A 3 DVDB Analog Input AC coupled input path B 4 DVDC Analog Input AC coupled input path C 5 DVDD Analog Input AC coupled input path D 6 DVDRFIP Analog Input AC coupled DVD RF signal input RFIP 7 DVDRFIN Analog Input AC coupled DVD RF signal input RFIN 8 MA Analog Input DC coupled main-beam RF signal input A 9 MB Analog Input DC coupled main-beam RF signal input B 10 MC Analog Input DC coupled main-beam RF signal input C 11 MD Analog Input DC coupled main-beam RF signal input D 12 SA Analog Input DC coupled sub-beam RF signal input A 13 SB Analog Input DC coupled sub-beam RF signal input B 14 SC Analog Input DC coupled sub-beam RF signal inputC 15 SD Analog Input DC coupled sub-beam RF signal input D 16 SDFON Analog Input CD focusing error negative input 17 SDFOP Analog Input CD focusing error positive input 18 TNI Analog Input 3 beam satellite PD signal negative input 19 TPI Analog Input 3 beam satellite PD signal positive input 20 MDI1 Analog Input Laser power monitor input 21 MDI2 Analog Input Laser power monitor input 22 LDO1 Analog Output Laser driver output 23 LDO2 Analog Output Laser driver output 24 SVDD3 Power Analog 3.3V power 25 CSO Analog Output Central servo 26 RFLVL Analog Output RFRP low pass output 27 SGND Ground Ground pin for analog circuitry 28 V2REFO Analog Output Reference voltage 2.8V 29 V20 Analog Output Reference voltage 2.0V 30 VREFO Analog Output Reference voltage 1.4V 31 FEO Analog Output Focus error monitor output 32 TEO Analog Output Tracking error monitor output 33 TEZISLV Analog Output TE Slicing Level 34 OP_OUT Analog Output OP amp output 35 OP_INN Analog Input OP amp negative input 36 OP_INP Analog Input OP amp positive input 37 DMO Analog Output Disc motor control output.PWM output 38 FMO Analog Output Feed motor control. PWM output 39 TROPENPWM Analog Output Tray PWM output/Tray open output 40 IOP_MON Analog Input General A/D input -> IOP monitor 41 TRO Analog Output PDM output of tracking servo compensator 42 FOO Analog Output PDM output of focus servo compensator 43 SPFG Ground Ground pin for internal digital circuitry 44 MSW Output Not used 45 CKSW Input Not used 46 OCSW Output Open/Close 47 HA2 Output PU Host address bit 2 48 DVDD18 Power 1.8V power pin for internal digital circuity 5-1. SYSTEM CONTROL PIN FUNCTION (MV-47/48 BOARDS IC101) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 5-2 DVP-NS15/NS51P/NS43P/NS53P/K56P Pin No. Pin name Type Function 49 HA3 Output PU Host address bit 3 50 HA4 Output PU Host address bit 4 51 HA5 Output PU Host address bit 5 52 HA6 Output PU Host address bit 6 53 HA7 Output PU Host address bit 7 54 HA8 Output PU Host address bit 8 55 HA18 Output PD, SMT Host address bit 18 56 DVSS Ground Ground pin for internal digital circuitry 57 HA19 Output PD, SMT Host address bit 19 58 DVDD3 Power 3.3V power pin internal digital circuitry 59 XWR Output PU, SMT Write enable, active low 60 HA16 Output PU Host address bit 16 61 DVDD3 Power 3.3V power pin internal digital circuitry 62 HA15 Output PU Host address bit 15 63 HA14 Output PU Host address bit 14 64 HA13 Output PU Host address bit 13 65 HA12 Output PU Host address bit 12 66 HA11 Output PU Host address bit 11 67 HA10 Output PU Host address bit 10 68 HA9 Output PU Host address bit 9 69 HA20 Output PU, SMT Host address bit 20 70 XROMCS Output SMT Chip select (Active low) 71 DVSS Ground Ground pin for internal digital circuitry 72 HA1 Output PU Host address bit 1 73 XRD Output SMT Read enable, active low 74 DVSS Ground Ground pin for internal digital circuitry 75 HDD Output Host address bit 0 76 HD1 Output Host address bit 1 77 HD2 Output Host address bit 2 78 HD3 Output Host address bit 3 79 HD4 Output Host data bit 4 80 HD5 Output Host data bit 5 81 HD6 Output Host data bit 6 82 LIMITSW Input PD, SMT BU limit switch sensor input 83 ALE Output PU, SMT Address latch enable 84 DVDD18 Power 1.8V power pin for internal digital circuitry 85 HD7 Output Host data bit 7 86 HA17 Output PU Host address bit 17 87 DVDD3 Power 3.3V power pin for internal digital circuitry 88 HA0 Output PU Host address bit 0 89 UWR# Output PU, SMT 8032 write strobe 90 URD# Output PU, SMT 8032 read strobe 91 IFBSY Input PU, SMT Ext CPU ready/busy interrupt signal (H: Busy, L: Ready) 92 IFCK Output PU, SMT Ext CPU serial clock 93 EEWP Output PU, SMT EEPROM write protect control (H: WP enable, L: WP disable) 94 XIFCS Output, PU SMT Chip select for Ext CPU (Active low) 95 IFSDI Input PU, SMT Ext CPU serial data input 96 SCL In/Out PU, SMT Hardware IIC clock 97 DVSS Ground Ground pin for internal digital circuitry 98 SDA In/Out PU, SMT Hardware IIC data 99 TSD_M Input PU, SMT Motor driver thermal shutdown sensor (Active low) 100 IFSDO Output PU, SMT Ext CPU serial data output 101 RXD Input PU, SMT Hardware RS232C RXD 102 TXD Output PU, SMT Hardware RS232C TXD www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 5-3 DVP-NS15/NS51P/NS43P/NS53P/K56P Pin No. Pin name Type Function 103 MUTE Output PD, SMT Motor driver channel 4 mute 104 ICE Input PD, SMT ICE mode enable 105 XSYSRST Input PU, SMT MT1389D2 reset input (Active low) 106 IR Input SMT IR control signal input 107 INTO# In/Out PU, SMT 8032 external interrupt 0 (for ICE) 108 DVDD3 Power 3.3V power pin for internal digital circuitry 109 DQMO Output Mask for DRAM input/output byte 0 110 RD7 In/Out DRAM data bit 7 111 RD6 In/Out DRAM data bit 6 112 RD5 In/Out DRAM data bit 5 113 RD4 In/Out DRAM data bit 4 114 RD3 In/Out DRAM data bit 3 115 DVSS Ground Ground pin for internal digital circuitry 116 RD2 In/Out DRAM data bit 2 117 RD1 In/Out DRAM data bti 1 118 RD0 In/Out DRAM data bti 0 119 RD15 In/Out DRAM data bit 15 120 DVSS Ground Ground pin for internal digital circuitry 121 RD14 In/Out DRAM data bit 14 122 RD13 In/Out DRAM data bit 13 123 DVDD3 Power 3.3V power pin for internal digital circuitry 124 RD12 In/Out DRAM data bit 12 125 RD11 In/Out DRAM data bit 11 126 RD10 In/Out DRAM data bit 10 127 RD9 In/Out DRAM data bit 9 128 RD8 In/Out DRAM data bit 8 129 DQM1 Output Mask for DRAM input/output byte 1 130 DVSS Ground Ground pin for internal circuitry 131 RWE# Output DRAM write enable 132 CAS# Output DRAM collumn address strobe 133 DVDD18 Power 1.8V power pin for internal digital circuitry 134 RAS# Output DRAM row address strobe 135 RCS# Output DRAM chip select 136 BA0 Output DRAM bank address 0 137 BA1 Output DRAM bank address 1 138 DVDD3 Power 3.3V power pin for internal digital circuitry 139 RA10 Output DRAM address bit 10 140 RA0 Output DRAM address bit 0 141 RA1 Output DRAM address bit 1 142 RA2 Output DRAM address bit 2 143 DVSS Ground Ground pin for internal circuitry 144 RA3 Output DRAM address bit 3 145 DVSS Ground Ground pin for internal circuitry 146 DRCLK Output DRAM clock 147 CKE Output DRAM clock enable 148 RA11 Output DRAM address bit 11 149 RA9 Output DRAM address bit 9 150 RA8 Output DRAM address bit 8 151 DVDD3 Ground Ground pin for internal digital circuitry 152 RA7 Output DRAM address bit 7 153 RA6 Output DRAM address bit 6 154 RA5 Output DRAM address bit 5 155 RA4 Output DRAM address bit 4 156 DVDD18 Ground 1.8V power pin for internal digital circuitry www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 5-4 DVP-NS15/NS51P/NS43P/NS53P/K56P Pin No. Pin name Type Function 157 FWD Output Loading control signal (Forward) 158 REV Output Loading control signal (Reverse) 159 MUTE123 Output Motor driver channel 1,2 & 3 mute 160 DVSS Ground Ground pin for internal digital circuitry 161 RGBSEL (DVP-NS15 only) Output RGB/YCbCr select output signal (H: RGB Disabled, L: RGB Enabled) MIC (DVP-K56P only) Input Karaoke microphone detect signal (Active high) 162 DSEL (DVP-NS53P (Japan) only) Output SMT Interlace/Progressive select output signal (H: 480i, L: 480P) (not connected) KRMOD (DVP-K56P only) Output SMT Karaoke mode status output (H: Karaoke, L: Normal) 163 COMP_MUTE Output PD, SMT Video component output mute (H: CVBS, S-Vid out, L: Component out) 164 XECHO Input PD, SMT Karaoke echo function control (H: Echo off, L: Echo) 165 XMAMUTE Output PD, SMT Main audio mute signal (Active low) 166 EUROVY Output PD, SMT CVBS/S-terminal select output signal (H: CVBS, L: S-terminal) 167 DISC/xEXT Output PD, SMT Disc/External input select output signal (H: Disc, L: External) 168 DVDD3 Power 3.3V power pin for internal digital circuitry 169 WIDE Output Video aspect ratio control SW 170 SPDIF Output SPDIF output 171 DACVDDC Power 3.3V power for Video DAC circuitry 172 VREF Analog Bandgap reference voltage 173 FS Analog Full scale adjustment 174 DACVSSC Ground Ground pin for Video DAC circuitry 175 CVBS Output Analog composite out 176 DACVDDB Power 3.3V power for Video DAC circuitry 177 DACVSSB Ground Ground pin for Video DAC circuitry 178 DACVDDA Power 3.3V power for Video DAC circuitry 179 Y/G Output Green signal or Y Signal output 180 DACVSSA Ground Ground pin for Video DAC circuitry 181 B/Cb/Pb Output Blue signal or Cb signal output 182 R/Cr/Pr Output Red signal or Cr signal output 183 APLLVDD3 Power 3.3V power for audio clock circuitry 184 APLLCAP Analog Inout APLL external capacitance connection 185 APLLVSS Ground Ground pin for audio clock circuitry 186 ADACVDD3 Power 3.3V power for internal AudioDAC circuitry 187 AR Output Analog audio output Rch 188 VCM Analog Audio DAC reference voltage 189 AL Output Analog audio output Lch 190 ADACGND Ground Ground pin for internal AudioDAC circuitry 191 RFGND18 Ground Ground pin for RF digital circuitry 192 RFVDD18 Power 1.8V power pin for internal analog circuitry 193 XTALO Output 27MHz crystal output 194 XTALI Input 27MHz crystal input 195 JITFO Analog Output Output terminal for RF jitter 196 JITFN Analog Input Input terminal for RF jitter 197 PLLVSS Ground Ground pin for data PLL and related analog circuitry 198 IDACEXLP Analog Output Data PLL DAC Low-pass filter 199 PLLVDD3 Power 3.3V power for data PLL & related analog circuitry 200 LPFON Analog Output Negative output of loop filter amplifier 201 LPFIP Analog Input Positive input of loop filter amplifier 202 LPFIN Analog Intput Negative input of loop filter amplifier 203 LPFOP Analog Output Positive output of loop filter amplifier 204 ADCVDD3 Power Power pin for ADC circuitry 205 ADCVSS Ground Ground pin for ADC circuitry 206 RFVDD3 Power 3.3V power pin for RF digital circuitry 207 RFRPDC Analog Output RF ripple detect output www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 5-5 DVP-NS15/NS51P/NS43P/NS53P/K56P Pin No. Pin name Type Function 208 RFRPAC Analog Input RF ripple detect input (through AC-coupling) 209 HRFZC Analog Input High frequency RF ripple zero crossing 210 CRTPLP Analog Output Defect level filter capacitor connecting 211 RFGND Ground Ground pin for RF digital circuitry 212 NC Analog Output RF offset cancellation capacitor connection 213 NC Analog Output RF offset cancellation capacitor connection 214 OSP Analog Output RF AGC loop capacitor connection for DVD-ROM 215 OSN Analog Input Reference current input 216 RFGC Power 3.3V power pin for analog circuitry 5-5E www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 6-1 DVP-NS15/NS51P/NS43P/NS53P/K56P SECTION 6 TEST MODE 6-1. EXECUTING IOP MEASUREMENT In order to execute IOP measurement, the following standard procedures must be followed. (1) In standby mode, press [TOP MENU], [CLEAR], [POWER] to enter Remocon Diagnosis Mode. Remocon Diagnosis Menu 0. External Chip Check 1. Servo Parameter Check 2. Drive Manual Operation 3. Emergency History 4. Version information 5. Video Level Adjustment Model : xxx xxx xxx IF-con Ver : xxx Syscon Ver : xxx (2) Select “2. Drive Manual Operation” by pressing the 2 key on the remote commander. The screen will appear as below. Drive Manual Operation 1. Servo Control 2. Track/Layer Jump 3. Manual Adjustment 4. Tray Aging Mode 0. Return to top Menu (3) Select “3. Manual Adjustment” by pressing the 3 key on the remote commander. The screen will appear as below. Manual Adjust 1. Track Balance Adjust: 2. Track Gain Adjust: 3. Focus Balance Adjust: 4. Focus Gain Adjust: 5. Eg boost Adjust: 6. Iop: 7. TRV. Level: 8. S curve(FE) Level: 9. RFL(PI) Level: 0. MIRR Time: $4 Change Value [RETURN] Return to previous menu (4) Select Iop by pressing 6 key on the remote commander. (5) Wait until a hexadecimal number appear. Manual Adjust 1. Track Balance Adjust: 2. Track Gain Adjust: 3. Focus Balance Adjust: 4. Focus Gain Adjust: 5. Eq Boost Adjust: 6. Iop. ED: 7. TRV. Level: 8. S curve(FE) Level: 9. RFL(PI) Level: 0. MIRR Time: $4 Change Value [RETURN] Return to previous menu (6) Convert data from hexadecimal to decimal. (7) Use the following formula to calculate IOP in mA IOP (mA)=IOP (decimal) x 0.622678. (8) Press [RETURN] to return back to previous menu. (9) Press - to return to Top Menu and power OFF the DVD Player. 6-2. EMERGENCY HISTORY CHECK Information of Emergency History. (1) In standby mode, press [TOP MENU], [CLEAR], [POWER] to enter Remocon Diagnosis Mode. (2) Select “3. Emergency History”. Emg. History Check Laser Hours CD 999h 59min DVD 999h 59min 1. 01 05 04 04 00 92 46 00 00 00 00 00 00 00 23 45 2. 02 02 01 01 00 A9 4B 00 00 00 00 00 00 00 23 45 [Next] Next Page [Prev] Prev Page - Return to Top Menu (3) Laser Hours DVD Laser ON time. (Total ON time) CD Laser ON time. (Total ON time) (4) Emergency History The history information from last “1” to “10” can be scrolled with [NEXT] key or [PREV] key. (5) Error code Example of Error code 1. 01 05 04 04 00 92 46 00 00 00 00 00 00 00 23 45 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 6-2 DVP-NS15/NS51P/NS43P/NS53P/K56P (6) Error code list 01: Communication error (No reply from syscon) 02: Syscon hung up 03: Power OFF request when syscon hung up 19: Thermal shutdown 24: MoveSledHome error 25: Mecha move error (5 Changer) 26: Mecha move stack error 30: DC Motor adjustment error 31: DPD offset adjustment error 32: TE Balance adjustment error 33. TE Sensor adjustment error 34. TE loop gain adjustment error 35. FE loop gain adjustment error 36. Bad jitter after adjustment 40. Focus NG 42. Focus Layer Jump NG 52. Open kick spindle error 51: Spindle stop error 60: Focus on error 61: Seek fail error 62: read Qdata/ID error 70: Lead In Data Read Fail 71: TOC read time out (CD) 80: Can’t Buffering 81: Unknown media type (7) Error code parameters Example of Error code 1. 01 05 04 04 00 92 46 00 00 00 00 00 00 00 23 45 This is the detailed contents of error information (8) Laser hours at error happend. Example of Error code 1. 01 05 04 04 00 92 46 00 00 00 00 00 00 00 23 45 This is Laser hours when an error happened. (9) How to Clear laser hours Press [DISPLAY], [CLEAR] keys in this order. Both CD and DVD data are cleared. Emg. History Check Laser Hours CD 0h 0min DVD 0h 0min 1. 01 05 04 04 00 92 46 00 00 00 00 00 00 00 23 45 2. 02 02 01 01 00 A9 4B 00 00 00 00 00 00 00 23 45 [Next] Next Page [Prev] Prev Page - Return to Top Menu (10) How to Clearing Emergency code Press [TOPMENU], [CLEAR] keys in this order. All emergency code are cleared. Emg. History Check Laser Hours CD 999h 59min DVD 999h 59min 1. 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 2. 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 [Next] Next Page [Prev] Prev Page (11) Press - key, return to TOP MENU. 6-3. INITIALIZING SETUP DATA How to initializing setup data. (1) In standby mode, press [TOP MENU], [CLEAR], [POWER] to enter Remocon Diagnosis Mode. (2) Select “3. Emergency History”. Emg. History Check Laser Hours CD 999h 59min DVD 999h 59min 1. 01 05 04 04 00 92 46 00 00 00 00 00 00 00 23 45 2. 02 02 01 01 00 A9 4B 00 00 00 00 00 00 00 23 45 [Next] Next Page [Prev] Prev Page - Return to Top Menu (3) Initializing setup data Press [MENU], [CLEAR] keys in this order. The data have been initialized when “Initialize setup data...” mesage is displayed. Emg. History Check Laser Hours CD 999h 59min DVD 999h 59min Initialize setup data ... [Next] Next Page [Prev] Prev Page - Return to Top Menu www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 6-3 DVP-NS15/NS51P/NS43P/NS53P/K56P (4) The Emergency history display screen will be restored soon. Emg. History Check Laser Hours CD 999h 59min DVD 999h 59min 1. 01 05 04 04 00 92 46 00 00 00 00 00 00 00 23 45 2. 02 02 01 01 00 A9 4B 00 00 00 00 00 00 00 23 45 [Next] Next Page [Prev] Prev Page (12) Press - key, return to TOP MENU. 6-4. VERSION INFORMATION Information of firmware version. (1) In standby mode, press [TOP MENU], [CLEAR], [POWER] to enter Remocon Diagnosis Mode. (2) Select “4. Version Information”. Version information Firm (Main) : Ver. xxxxx Firm (Sub) : xxxxx RISC : xxxxx 8032 : xxxxx Audio DSP : xxxxx Servo DSP : xxxxx - Return to Top Menu (3) Press - key, return to TOP MENU. 6-5. IF CON SELF DIAGNOSTIC FUNCTION 1. IF-144/IF-145 BOARDS (IF CON) TEXT MODE The IF-144/IF-145 boards (IF CON) test mode is the IF CON self-diagnosis mode. The IF CON can diagnose the functions of the IF-144/IF-145 boards that the IF CON controls. Normally, the IF CON makes a serial communication with the SYSTEM CONTROL and operates following the commands from the SYSTEM CONTROL, but in the Test mode, the IF CON operates independently from the SYSTEM CONTROL. In the test mode, the following functions can be checked. 1. Button function 2. Remote commander receiving function 3. SYSTEM CONTROL-IF CON serial communication 4. Fluorescent display tube lighting check - Grid check - Anode check 5. LED control function In the test mode, the main unit operates same as usual, except voltage monitoring, communication, display of fluorescent display tube, and LED control. 1. The routine that monitors +3.3V (PCONT) of MV-47/MV-48 boards is not provided. 2. The monitoring timer for serial communication with the SYSTEM CONTROL is not provided. The main unit is not placed in the Standby mode, even if the communication with SYSTEM CONTROL is normal. 3. Display of fluorescent display tube. (Normally, display is mode following the commands from SYSTEM CONTROL). 4. LED control. (Normally, control is mode made following the commands from SYSTEM CONTROL). 2. OPERATION OF SELF CHECK MODE The Self Check mode is the function to conduct the basic test to the FL display and DVD panel section. 2-1. Self Check Mode Transition Processing At the AC Power ON after reset of IF CON is released, while pressing with the MV-47/MV-48 boards are not connected to the IF-144/ IF-145 boards, or while pressing the x key on the main unit with the IF CON in STANDBY mode, enter [RETURN] t [DISPLAY] (or [SETUP]) on the remote commander, and the main unit transits to the Self Check Mode. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 6-4 DVP-NS15/NS51P/NS43P/NS53P/K56P 2-2. Operation of Auto Self Check When the Self Check mode becomes active at the AC Power ON or by key input, the test display of the following steps (1) to (4) is repeated. (1) FLD and LED all ON (for 5 seconds) (2) MODEL display (for 2 seconds) (DVP-NS51P) MODEL display (for 2 seconds) (DVP-NS43P/NS53P) MODEL display (for 2 seconds) (DVP-K56P) 3) Version display (for 2 seconds) (4) ROM creation date display (for 2 seconds) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 6-5 DVP-NS15/NS51P/NS43P/NS53P/K56P (2-3. Each Self Check Function Each Self Check function tests the FLD display, LED display, and key input. 2-3-1. FLD and LED All ON 2-3-1-1. Transition Keys in Self Check Mode • Z key and x key on the main unit • T key on the remote commander 2-3-1-2. Operation and display In this mode, all LEDs and all segments of FLD turn ON. • Example of FLD all ON (EXCEPT DVP-NS15) Input IC404: Pin No. (Signal) Voltage [V] PIN ef (AD1) PIN eg (O/C) PIN eh (STOP) PIN ej 0 - 0.20 PLAY OPEN/CLOSE STOP POWER 0.60 - 0.82 - - PROGRESSIVE - 1.16 - 1.47 PREVIOUS - - - 1.80 - 2.12 NEXT - - - 2.48 - 2.70 - - - - www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 6-6 DVP-NS15/NS51P/NS43P/NS53P/K56P 2-3-2. Main Unit Key Name Display and Key Code Display 2-3-2-1. Transition Keys in Self Check Mode • Keys on the main unit except keys transited in Self Check Mode 2-3-2-2. Operation and Display When a key on the main unit is pressed in the Self Check mode, the name of that key is displayed on the FLD. Aslo, the key name display and the key code display can be switched with the [DISPLAY] key on the remote commander, “NOTHING” is displayed when nothing is entered. Also, DVD, V, CD segments turn on when a communication error occurred. • FLD display (at input of H key on the main unit)•Key code display (at input of H key, key code: 0Ah) • At input of faulty voltage • When key is pressed double 2-3-3. Remote Commander Key Name Display and Key Code Display 2-3-3-1. Transition Keys in Self Check Mode • Remote commander keys except keys transited in Self Check Mode 2-3-3-2. Operation and Display When a key on the remote commander is pressed in the Self Check Mode, the name of that key is displayed on the FLD. Aslo, the key name display and the key code display can be switched with the [DISPLAY] key on the remote commander. “NOTHING” is displayed when nothing is entered. Also, VIDEO CD, DVD, and CD segments turn on when a communication error occurred. • Remote commander key name display (at input of X key) • Remote commander key code display (at input of X key, key code:39h) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 6-7 DVP-NS15/NS51P/NS43P/NS53P/K56P 2-3-4. Communication Monitoring Display The communication state is monitored and displayed while the key name on the main unit and the remote commander is displayed. When the communication to the System Controller failed, VIDEO CD, DVD, and CD segments turn on. • Communication error display (at no input of key and remote commander) • Communication error display (at code display without input of the remote commander) 2-3-5. FLD Anode Test Display and SHUTTLE Click Operation Test 2-3-5-1. Transition Keys in Self Check Mode • t key on the remote commander • SHUTTLE on the remote commander during Anode Test display (This unit does not provide JOG/SHUTTLE, and therefore use another DVD remote commander having the JOG/SHUTTLE) 2-3-5-2. Operation and Display The Self Check Mode transits to this mode when t key is entered. This tests whether each segment turns on individually. Only the first segment of each grid of FLD turns on, and each time the SHUTTLE is entered, the segment of each grid switched in order. When SHUTTLE input is clockwise, the segment switches in 1 - 2 -3 direction, or counterclockwise it switches in 3 - 2- 1 direction. • Display at the start of Anode Test r (Input in CW direction) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 6-8 DVP-NS15/NS51P/NS43P/NS53P/K56P 2-3-6. FLD Grid Test Display and SHUTTLE Click Operation Test 2-3-6-1. Transition Keys in Self Check Mode • R key on the remote commander • SHUTTLE on the remote commander during Grid Test display (This unit does not provide JOG/SHUTTLE, and therefore use another DVD remote commander having the JOG/SHUTTLE) 2-3-6-2. Operation and Display The Self Check Mode transits to this mode when R key is entered. This tests whether each grid turns on individually. The first grid only of FLD turns on and other grid turn off. Each time the SHUTTLE is entered, the grid is switched in order. When SHUTTLE input is clockwise, the grid switched in 1 - 2 - 3 direction, or counterclockwise it switches in 3 - 2 - 1 direction. • Display at the start of Grid Test 2-3-7. LED Test Display 2-3-7-1. Transition Keys in Self Check Mode • r key on the remote commander • SHUTTLE on the remote commander during Grid Test display (This model does not provide JOG/SHUTTLE, and therefore use another DVD remote commander having the JOG/SHUTTLE) 2-3-7-2. Operation and Display LED is switched in order by the input JOG/SHUTTLE on the remote commander. Also, LED ON/OFF is switched by the input of same key as the function that turns on the LED conncerned. • FLD display during LED Test r (Input in CW direction) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 6-9 DVP-NS15/NS51P/NS43P/NS53P/K56P 7G 6G 5G 4G 3G 2G 1G col - col - - - - - - - - - - - - - - Dp Dp Dp Dp Dp Dp a a a a a a a k k k k k k k j j j j j j j h h h h h h h b b b b b b b f f f f f f f m m m m m m m s s s s s s s g g g g g g g c c c c c c c d d d d d d d r r r r r r r p p p p p p p n n n n n n n e e e e e e e 6G 2G 1G 6G 7G 5G 4G 3G 2G Dp (7G, 4G) (7G~3G, 1G) col (7G~1G) ANODE CONNECTION P1 P2 P3 P4 P5 P6 P7 P8 P9 P10 P11 P12 P13 P14 P15 P16 P17 P18 P19 P20 a f h g e r p n s c m d j k b 6-9E www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 7-1 DVP-NS15/NS51P/NS43P/NS53P/K56P This section describes procedures and instructions necessary for adjusting electrical circuits in this unit. Instruments required: (1) Color monitor TV (2) Oscilloscope 1 or 2 phenomena, band width over 100 MHz, with delay mode (3) Frequency counter (over 8 digits) (4) Digital multimeter (5) Standard commander (RMT-D175A/RMT-D175P) (6) DVD reference disc HLX-501 (J-6090-071-A) (dual layer) (NTSC) HLX-503 (J-6090-069-A) (single layer) (NTSC) HLX-504 (J-6090-088-A) (single layer) (NTSC) HLX-505 (J-6090-089-A) (dual layer) (NTSC) 7-1. POWER SUPPLY OUTPUT VOLTAGE CHECK Mode Except standby Instrument Digital multimeter EVER +5 V Check Test point CN201 pin 4 Specification 5.0 ± 0.3 Vdc SW +3.3 V Check Test point CN201 pin 5 Specification 3.35 ± 0.2 Vdc SW+5 V Check Test point CN201 pin 6 Specification 5.0 Vdc SW +8 V Check Test point CN201 pin 1 Specification 8.0 ± 0.5 Vdc EVER +11 V Check Test point CN201 pin 3 Specification 11.0 Vdc EVER –10 V Check Test point CN201 pin q; Specification –10.0 Vdc Checking method: (1) Confirm that each voltage satisfies the specification. +0.5 –1.0 +1.0 –0.5 +0.2 –0.3 SECTION 7 ELECTRICAL ADJUSTMENT www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 7-2 DVP-NS15/NS51P/NS43P/NS53P/K56P A 7-2. ADJUSTMENT OF VIDEO SYSTEM (DVP-NS15) 1. Checking Scart Video Output Level (Video Mode) Checking Video Level the NTSC/PAL standard, and if not correct, the brightness will be too large or small. Mode HLX-504 play back Signal Color bars 100% Test point VIDEO OUT (19p) connector (75 W terminated) Instrument Oscilloscope Specification 1.0 ± 0.08 Vp-p Adjusting method: (1) In the Video Signal menu “1” Color Bar 100% play back. (2) Confirm that the Y level is 1.0 ± 0.08 Vp-p. Fig. 7-2. 2. Checking Scart S Video Output S-Y (S-Video Mode) Check S-terminal video output. If it is incorrect, pictures will not be displayed correctly in spite of connection to the TV with a S-terminal cable. Mode HLX-504 play back Signal Color bars 100% Test point S VIDEO OUT (S-Y) (19p) (75 Ω terminated) Instrument Oscilloscope Specification 1.0 ± 0.08 Vp-p Checking method: 1) In the Video Signal menu “1” Color Bar 100% play back. 2) Confirm that the S-Y level is 1.0 ± 0.08 Vp-p. Fig. 7-3. 3. Checking Scart S Video Output S-C (S-Video Mode) This checks whether the S-C satisfies the NTSC/PAL standard. If it is not correct, the colors will be too dark or light. Mode HLX-504 play back Signal Color bars 100% Test point S VIDEO OUT (S-C) (15p) (75 Ω terminated) Instrument Oscilloscope Specification A = 286 ± 50 mVp-p (NTSC) A = 300 ± 50 mVp-p (PAL) Checking method: (1) In the Video Signal menu “1” Color Bar 100% play back. (2) Confirm that the S-C burst is “A”. Fig. 7-4. 4. Checking RGB Output G (RGB Mode) This checks RGB video output G level. If it is incorrect, correct color will not be remain some. Mode HLX-504 play back Signal Color bars Test point Green Out (11p) (75 Ω terminated) Instrument Oscilloscope Specification A = 700 ± 70mVp-p Checking method: (1) In the Video Signal menu “1” Color Bar 100% play back. (2) Confirm that the G level is 1.0 ± 0.08 Vp-p. Fig. 7-5. A 1.0 ± 0.08 Vp-p 1.0 ±0.08 Vp-p www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 7-3 DVP-NS15/NS51P/NS43P/NS53P/K56P 5. Checking RGB Output B (RGB Mode) This checks RGB video output B level. If it is incorrect, correct colors will not be displayed when connected to, for instance, projector. Mode HLX-504 play back Signal Color bars Test point Blue Out, (7p) (75 Ω terminated) Instrument Oscilloscope Specification B = 700 ± 70 mVp-p Checking method: (1) In the Video Signal menu “1” Color Bar 100% play back. (2) Confirm that the B level is A. Fig. 7-6. 6. Checking RGB Output R (RGB Mode) This checks RGB video output R level. If it is incorrect, correct colors will not be displayed when connected to, for instance, projector. Mode HLX-504 play back Signal Color bars Test point Red Out, (15p) (75 Ω terminated) Instrument Oscilloscope Specification C = 700 ± 70 mVp-p Checking method: (1) In the Video Signal menu “1” Color Bar 100% play back. (2) Confirm that the R level is B. Fig. 7-7. B C 7-3. ADJUSTMENT OF VIDEO SYSTEM (EXCEPT DVP-NS15) 1. Checking Video Level Checking Video Level the NTSC/PAL standard, and if not correct, the brightness will be too large or small. Mode HLX-504 play back Signal Color bars 100% Test point LINE OUT (VIDEO) connector (75 Ω terminated) Instrument Oscilloscope Specification 1.0 ± 0.08 Vp-p Adjusting method: (1) In the Video Signal menu “1” Color Bar 100% play back. (2) Confirm that the Video Level is 1.0 ± 0.08 Vp-p. Fig. 7-1. 2. Checking S Video Output S-Y Check S-terminal video output. If it is incorrect, pictures will not be displayed correctly in spite of connection to the TV with a S-terminal cable. Mode HLX-504 play back Signal Color bars 100% Test point S VIDEO OUT (S-Y) connector (75 Ω terminated) Instrument Oscilloscope Specification 1.0 ± 0.08 Vp-p Checking method: (1) In the Video Signal menu “1” Color Bar 100% play back. (2) Confirm that the S-Y level is 1.0 ± 0.08 Vp-p. Fig. 7-2. 1.0 ± 0.08 Vp-p 1.0 ±0.08 Vp-p www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 7-4 DVP-NS15/NS51P/NS43P/NS53P/K56P 1.0 ±0.08 Vp-p A B 3. Checking S Video Output S-C This checks whether the S-C satisfies the NTSC/PAL standard. If it is not correct, the colors will be too dark or light. Mode HLX-504 play back Signal Color bars 100% Test point S VIDEO OUT (S-C) connector (75 Ω terminated) Instrument Oscilloscope Specification A = 286 ± 50 mVp-p (NTSC) A = 300 ± 50 mVp-p (PAL) Checking method: (1) In the Video Signal menu “1” Color Bar 100% play back. (2) Confirm that the S-C burst is “A”. Fig. 7-3. 4. Checking Component Video Output Y This checks component video output Y. If it is incorrect, correct brightness will not be attained when connected to, for instance, projector. Mode HLX-504 play back Signal Color bars Test point COMPONENT VIDEO OUT (Y) connector, (75 Ω terminated) Instrument Oscilloscope Specification 1.0 ± 0.08 Vp-p Checking method: (1) In the Video Signal menu “1” Color Bar 100% play back. (2) Confirm that the Y level is 1.0 ± 0.08 Vp-p. Fig. 7-4. 5. Checking Component Video Output B-Y This checks component video output B-Y. If it is incorrect, correct colors will not be displayed when connected to, for instance, projector. Mode HLX-504 play back Signal Color bars Test point COMPONENT VIDEO OUT (PB) connector (75 Ω terminated) Instrument Oscilloscope Specification A = 700 ± 70 mVp-p Checking method: (1) In the Video Signal menu “1” Color Bar 100% play back. (2) Confirm that the B-Y level is A. Fig. 7-5. 6. Checking Component Video Output R-Y This checks component video output R-Y. If it is incorrect, correct colors will not be displayed when connected to, for instance, projector. Mode HLX-504 play back Signal Color bars Test point COMPONENT VIDEO OUT (PR) connector (75 Ω terminated) Instrument Oscilloscope Specification B = 700 ± 70 mVp-p Checking method: (1) In the Video Signal menu “1” Color Bar 100% play back. (2) Confirm that the R-Y level is B. Fig. 7-6. A 7-4E www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 8-1 DVP-NS15/NS51P/NS43P/NS53P/K56P SECTION 8 REPAIR PARTS LIST NOTE: • -XX and -X mean standardized parts, so they may have some difference from the original one. • Items marked “*” are not stocked since they are seldom required for routine service. Some delay should be anticipated when ordering these items. • The mechanical parts with no reference number in the exploded views are not supplied. • Color Indication of Appearance Parts Example: KNOB, BALANCE (WHITE) . . . (RED) R R Parts Color Cabinet's Color 8-1. EXPLODED VIEWS • Abbreviation AEP : AEP Model AR : Argentina Model AUS : Australia/NZ Model BR : Brazilian Model CH : Chinese Model E : Latin America Model EA : Saudi Arabia Model HK : Hong Kong Model IN : India Model IR : Iran Model KR : Korean Model The components identified by mark or dotted line with mark are critical for safety. Replace only with part number specified. ME2 : Middle East Model ME5 : IND,PAK,MAR Model MX : Mexican Model MY : Malaysian Model RUS : Russian Model SP : Singapore Model TW : Taiwan Model UK : UK Model VN : Vietnam Model 8-1-1. MAIN SECTION ns : not supplied a). (NS51P/NS43P/NS53P) f g a o n 3 qa qa m qj m qg o p I qf 5 3 a q; 1 2 l 7 qj 6 h 4 qa qd NS53P/NS43P j h f g qs 8 a j ns ns ns ns ns qa ns 9 3 4 NS51P ONLY j j ns 9 NS53P/NS43P NS51P ONLY www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 8-2 DVP-NS15/NS51P/NS43P/NS53P/K56P Ref. No. Part No. Description Remark 1 3-070-883-31 SCREW, TAPPING BLACK 1 3-070-883-41 SCREW, TAPPING SILVER 2 A-1158-160-A SERVICE ASSY, CASE UPPER SILVER 2 A-1158-161-A SERVICE ASSY, CASE UPPER BLACK 3 2-666-787-01 COVER, TRAY (P) (NS51P: EXCEPT VN,CH) 3 2-666-787-31 COVER, TRAY (P) (NS51P:VN,CH) 3 2-660-717-11 COVER, TRAY (NS53P:MX,E) 3 2-660-717-21 COVER, TRAY (NS53P:AR,BR) 3 2-660-717-31 COVER, TRAY (NS43P) 4 X-2108-303-3 PANEL ASSY, FRONT SILVER (NS51P: EXCEPT CH,VN) 4 X-2108-334-3 PANEL ASSY, FRONT (NS51P:VN) SILVER 4 X-2108-335-1 PANEL ASSY, FRONT (NS51P:CH) SILVER 4 X-2108-336-1 PANEL ASSY, FRONT (NS51P:CH) BLACK 4 X-2108-304-3 PANEL ASSY, FRONT (NS51P:MY,EA,AUS) BLACK 4 X-2103-132-1 PANEL ASSY, FRONT (NS53P:MX,E) 4 A-1157-405-A PANEL ASSY, FRONT (NS53P:AR,BR) 4 A-1156-137-A PANEL ASSY,FRONT (NS43P) 5 3-087-053-01 +BVTP2.6 (3CR) 6 3-077-331-11 +BV3 (3-CR) 7 1-828-450-11 POWER-SUPPLY CORD (NS43P:BR/NS53P:E,BR/ NS51P: EXCEPT AUS,KR,HK,TW,CH) 7 1-828-454-11 POWER-SUPPLY CORD (NS51P:HK) 7 1-828-845-11 POWER-SUPPLY CORD (NS51P:TW) 7 1-828-871-11 POWER-SUPPLY CORD (NS51P:KR) 7 1-828-452-11 POWER-SUPPLY CORD (NS51P:AUS) 7 1-828-454-11 POWER-SUPPLY CORD (NS51P:HK) 7 1-828-460-11 POWER-SUPPLY CORD (NS43P:AR/NS53P:AR) 7 1-828-901-12 POWER-SUPPLY CORD (NS51P:CH) 7 1-828-451-11 POWER-SUPPLY CORD (NS53P:MX) 8 1-831-523-11 CABLE, FLEXIBLE FLAT (FMO-009) 9 1-831-569-11 CABLE, FLEXIBLE FLAT (FSW-002) 9 1-831-522-11 CABLE, FLEXIBLE FLAT (FSW-001) (NS43P/NS53P) * 10 1-831-524-11 CABLE, FLEXIBLE FLAT (FMS-010) 11 3-077-331-21 +BV3 (3-CR) 12 A-1168-959-A SERVICE ASSY, MV (NS51P:KR,TW,HK,SP,MY) 12 A-1169-005-A SERVICE ASSY, MV (NS51P:ME2,EA,IR) 12 A-1169-024-A SERVICE ASSY, MV (NS51P:ME5,IN) 12 A-1169-011-A SERVICE ASSY, MV (NS51P:AUS) 12 A-1169-221-A SERVICE ASSY, MV (NS51P:CH) 12 A-1158-440-A SERVICE ASSY, MV (NS53P:MX) 12 A-1158-441-A SERVICE ASSY, MV (NS53P:E) 12 A-1158-299-A SERVICE ASSY, MV (NS53P:AR) 12 A-1158-297-A SERVICE ASSY, MV (NS53P:BR) 12 A-1158-300-A SERVICE ASSY, MV (NS43P:AR) 12 A-1158-298-A SERVICE ASSY, MV (NS43P:BR) 13 1-468-972-11 POWER SUPPLY BLOCK (N53P:MX) Note : The components identified by mark or dotted line with mark are critical for safety. Replace only with part number specified. (NS51P/NS43P/NS53P) 13 1-468-971-11 POWER SUPPLY BLOCK (NS51P/NS43P/NS53P:EXCEPT MX) 14 3-071-119-91 COVER, BATTERY (NS43P/NS53P) 14 3-081-834-21 BATTERY, COVER (SMK7G) (NS51P) 15 1-479-179-21 REMOTE COMMANDER (RMT-D175P) (NS51P:EXCEPT KR,TW,CH) 15 1-479-179-11 REMOTE COMMANDER (RMT-D175A) (NS51P:KR,TW/NS43P/NS53P) 15 1-479-671-11 REMOTE COMMANDER (RMT-D175C) (NS51P:CH) 17 3-710-901-71 TAPPING SCREW Ref. No. Part No. Description Remark (NS51P ONLY) 12 A-1169-457-A SERVICE ASSY, MV (NS51P:VN) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 8-3 DVP-NS15/NS51P/NS43P/NS53P/K56P (NS15) f g a l o h n 3 2 qa m qh m qg I qf q; 1 2 qh 6 5 h 4 f g qa 7 qs 8 qd o a j j ns ns ns ns ns qa 9 ns Ref. No. Part No. Description Remark 1 3-070-883-41 SCREW, TAPPING 2 A-1158-160-A SERVICE ASSY, CASE UPPER 3 2-666-781-01 COVER, TRAY (B) 4 X-2108-302-3 PANEL ASSY, FRONT 5 3-087-053-01 +BVTP2.6 (3CR) 6 3-077-331-11 +BV3 (3-CR) 7 1-828-450-11 POWER SUPPLY CORD (NS15: EXCEPT UK) 7 1-828-454-11 POWER-SUPPLY CORD (NS15:UK) 8 1-831-523-11 CABLE, FLEXIBLE FLAT (FMO-009) 9 1-831-569-11 CABLE, FLEXIBLE FLAT (FSW-002) * 10 1-831-524-11 CABLE, FLEXIBLE FLAT (FMS-010) 11 3-077-331-21 +BV3 (3-CR) 12 A-1168-526-A SERVICE ASSY, MV 13 1-468-971-31 POWER SUPPLY BLOCK 14 3-081-834-21 BATTERY COVER (SMK7G) 15 1-479-179-21 REMOTE COMMANDER (RMT-D175P) 16 3-710-901-71 TAPPING SCREW Ref. No. Part No. Description Remark Note : The components identified by mark or dotted line with mark are critical for safety. Replace only with part number specified. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 8-4 DVP-NS15/NS51P/NS43P/NS53P/K56P Ref. No. Part No. Description Remark 1 3-070-883-41 SCREW, TAPPING 2 A-1158-160-A SERVICE ASSY, CASE UPPER 3 2-660-717-01 COVER, TRAY 4 X-2108-002-1 PANEL ASSY, FRONT 5 3-087-053-01 +BVTP2.6 (3CR) 6 3-077-331-11 +BV3 (3-CR) 7 1-828-450-11 POWER SUPPLY CORD (K56P:SP,EA,RUS) 7 1-828-845-11 POWER SUPPLY CORD (K56P:TW) 8 1-831-523-11 CABLE, FLEXIBLE FLAT (FMO-009) 9 1-831-522-11 CABLE, FLEXIBLE FLAT (FSW-001) * 10 1-831-524-11 CABLE, FLEXIBLE FLAT (FMS-010) 11 3-077-331-21 +BV3 (3-CR) 12 A-1164-608-A SERVICE ASSY, MV (K56P:SP,TW) 12 A-1164-615-A SERVICE ASSY, MV (K56P:EA) 12 A-1164-990-A SERVICE ASSY, MV (K56P:RUS) Note : The components identified by mark or dotted line with mark are critical for safety. Replace only with part number specified. (K56P) f g a o n 3 qa qa m qj m qg o p p I qf a 1 2 l 7 qj 6 h 4 qh qa qa 5 5 qd j j h f g qs 8 a ns ns ns ns ns qa ns 9 q; Ref. No. Part No. Description Remark 13 1-468-971-11 POWER SUPPLY BLOCK 14 3-071-119-91 COVER, BATERY (K56P:TW) 14 3-081-834-21 BATTERY COVER (SMK7G) (EXCEPT K56P:TW) 15 1-479-179-21 REMOTE COMMANDER (RMT-D175P) (EXCEPT K56P:TW) 15 1-479-179-11 REMOTE COMMANDER (RMT-D175A) (K56P:TW) * 16 2-664-753-01 KNOB, VOLUME 17 3-710-901-71 TAPPING SCREW www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 8-5 DVP-NS15/NS51P/NS43P/NS53P/K56P 8-1-2. MECHANISM DECK ASSEMBLY ns : not supplied Ref. No. Part No. Description Remark 20 A-6071-669-A LOADING ASSY(M) 21 3-088-372-01 INSULATOR 22 3-087-599-01 INSULATOR SCREW 23 4-674-137-11 SCREW (PTP2X5) 24 3-088-371-01 BELT 25 4-974-725-11 SCREW (M1.7X2.5), P 26 8-820-321-05 DEVICE,OPTICAL KHM-313CAA/C2RP 21 21 20 22 22 22 21 22 21 23 24 26 25 ns ns ns ns ns ns ns ns ns ns ns www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 8-6 NOTE: • Due to standardization, replacements in the parts list may be different from the parts specified in the diagrams or the components used on the set. • -XX and -X mean standardized parts, so they may have some difference from the original one. • RESISTORS All resistors are in ohms. METAL: Metal-film resistor. METAL OXIDE: Metal oxide-film resistor. F: nonflammable • Not all of the parts for POWER BLOCK (HS12S2U) are listed. • Items marked * are not stocked since they are seldom required for routine service. Some delay should be anticipated when ordering these items. • SEMICONDUCTORS In each case, u: µ, for example: uA. . : µA. . uPA. . : µPA. . uPB. . : µPB. . uPC. . : µPC. . uPD. . : µPD. . • CAPACITORS uF: µF • COILS uH: µH • Abbreviation AEP : AEP Model AR : Argentina Model AUS : Australia/NZ Model BR : Brazilian Model CH : Chinese Model E : Latin America Model EA : Saudi Arabia Model HK : Hong Kong Model IN : India Model IR : Iran Model 8-2. ELECTRICAL PARTS LIST Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark KR : Korean Model ME2 : Middle East Model ME5 : IND,PAK,MAR Model MX : Mexican Model MY : Malaysian Model RUS : Russian Model SP : Singapore Model TW : Taiwan Model UK : UK Model VN : Vietnam Model The components identified by mark or dotted line with mark are critical for safety. Replace only with part number specified. When indicating parts by reference number, please include the board. DVP-NS15/NS51P/NS43P/NS53P/K56P IF-143 MOUNT PWB (NS15 ) IF-144 MOUNTED PWB (NS43P/NS53P/K56P) IF-145 MOUNTED PWB (NS51P) ******************* C401 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V (EXCEPT NS15) C403 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V (EXCEPT NS15) C404 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V (EXCEPT NS15) C405 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V (EXCEPT NS15) C406 1-163-009-91 CAP,CHIP CERAMIC 1000PF B 2012 C408 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V (EXCEPT NS51P/NS15) C409 1-104-665-91 ELECT 100UF 20.00% 25V (NS43P/NS53P/NS51P ONLY) C409 1-128-111-91 ELECT 100UF 20% 25V (K56P ONLY) C410 1-130-479-91 MYLAR 0.0047UF 5.00% 50V (EXCEPT NS15) C411 1-115-339-91 CERAMIC CHIP 0.1UF 10.00% 50V (EXCEPT NS15) C412 1-126-965-91 ELECT 22UF 20.00% 50V (NS51P ONLY) C413 1-115-339-91 CERAMIC CHIP 0.1UF 10.00% 50V (EXCEPT NS15) C414 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V C416 1-164-489-91 CERAMIC CHIP 0.22UF 10.00% 16V C417 1-164-489-91 CERAMIC CHIP 0.22UF 10.00% 16V C418 1-104-660-91 ELECT 47UF 20.00% 16V (NS51P/NS15 ONLY) C419 1-126-965-91 ELECT 22UF 20.00% 50V (NS43P/NS53P ONLY) C419 1-128-131-91 ELECT 22UF 20.00% 50V (K56P ONLY) C420 1-163-251-91 CERAMIC CHIP 100PF 5.00% 50V (EXCEPT NS51P/NS15) C421 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V (NS15 ONLY) C422 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V (NS15 ONLY) C423 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V (NS15 ONLY) C424 1-124-233-91 ELECT 10UF 20.00% 16V (NS15 ONLY) CN403 1-815-382-11 CONNECTOR, FPC/FFC 7P (EXCEPT NS15/NS51P) CN403 1-794-479-11 CONNECTOR, FPC/FFC 9P (NS15/NS51P) D402 6-501-193-01 DIODE 1SS355WTE-17 (EXCEPT NS15) D403 6-501-193-01 DIODE 1SS355WTE-17 (EXCEPT NS15) D406 6-500-021-01 DIODE MM3Z4V7ST1 (EXCEPT NS15) * ET401 1-537-738-21 TERMINAL, EARTH (NS51P/NS15) * ET402 1-537-738-21 TERMINAL, EARTH * ET403 1-537-738-21 TERMINAL, EARTH (EXCEPT NS51P/NS15) IC404 6-806-296-01 IC 86CK74AFG-6FP0 (EXCEPT NS15) IC404 6-806-379-01 IC 47C443MG-6G92(ELZ0 (NS15 ONLY) IC406 6-705-738-01 IC RPM7240-H13 (EXCEPT NS51P/NS15) IC407 6-702-302-01 IC TK11133CSCL-G IC408 6-704-114-01 IC S-80828CNUA-B8NT2G JR401 1-216-295-91 SHORT CHIP 0 (EXCEPTNS51P/NS15) JR402 1-216-295-91 SHORT CHIP 0 JR404 1-216-295-91 SHORT CHIP 0 (EXCEPT NS51P/NS15) JR405 1-216-295-91 SHORT CHIP 0 (EXCEPTNS15) JR406 1-216-295-91 SHORT CHIP 0 (EXCEPT NS15) IF-144 IF-145 IF-143 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 8-7 Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark DVP-NS15/NS51P/NS43P/NS53P/K56P JR407 1-216-295-91 SHORT CHIP 0 (EXCEPT NS15) JR408 1-216-295-91 SHORT CHIP 0 (EXCEPT NS51P/NS15) JR409 1-216-295-91 SHORT CHIP 0 (NS51P ONLY) JR410 1-216-295-91 SHORT CHIP 0 JR411 1-216-295-91 SHORT CHIP 0 L401 1-408-982-81 INDUCTOR 100UH (EXCEPT NS15) ND401 1-519-795-11 VACUUM FLUORESCENT DISPLAY (EXCEPT NS51P/NS15) ND401 1-519-868-11 VACUUM FLUORESCENT DISPLAY (EXCEPT NS51P/NS15) Q401 8-729-056-46 TRANSISTOR 2SC5053T100Q (EXCEPT -NS15) Q401 8-729-421-20 TRANSISTOR UN2211-TX (NS15 ONLY) Q402 8-729-056-46 TRANSISTOR 2SC5053T100Q (EXCEPT NS15) R401 1-216-073-91 RES, CHIP 10K (2012) (EXCEPT NS15) R402 1-216-073-91 RES, CHIP 10K (2012) (EXCEPT NS15) R403 1-216-025-91 RES-CHIP 100 5% 1/10W (EXCEPT NS15) R404 1-216-025-91 RES-CHIP 100 5% 1/10W (EXCEPT NS15) R404 1-216-025-11 RES-CHIP 100 5% 1/10W (NS15 ONLY) R405 1-216-073-91 RES, CHIP 10K (2012) (EXCEPT NS15) R406 1-216-025-91 RES-CHIP 100 5% 1/10W (EXCEPT NS15) R407 1-216-025-91 RES-CHIP 100 5% 1/10W (EXCEPT NS15) R408 1-216-025-91 RES-CHIP 100 5% 1/10W (EXCEPT NS15) R409 1-216-025-91 RES-CHIP 100 5% 1/10W (EXCEPT NS15) R411 1-216-025-91 RES-CHIP 100 5% 1/10W (EXCEPT NS15) R412 1-216-073-91 RES, CHIP 10K (2012) (NS43P/NS53P/K56P/NS51P ONLY) R413 1-216-073-91 RES, CHIP 10K (2012) (NS53P ONLY) R414 1-216-073-91 RES, CHIP 10K (2012) (EXCEPT NS51P/NS15) R415 1-216-073-91 RES-CHIP 10K 5% 1/10W (NS51P ONLY) R416 1-216-073-91 RES, CHIP 10K (2012) (EXCEPT NS15) R417 1-216-073-91 RES, CHIP 10K (2012) (EXCEPTNS15) R418 1-216-073-91 RES, CHIP 10K (2012) (EXCEPT (NS51P/NS15) R419 1-216-073-91 RES, CHIP 10K (2012) (EXCEPT NS15) R420 1-216-027-91 RES-CHIP 120 5% 1/10W (EXCEPT NS15) R421 1-216-013-91 RES-CHIP 33 5% 1/10W (EXCEPT NS15) R422 1-216-097-91 RES-CHIP 100K 5% 1/10W R423 1-216-065-91 RES-CHIP 4.7K 5% 1/10W (EXCEPT NS15) R423 1-216-073-91 RES-CHIP 10K 5% 1/10W (NS15 ONLY) R424 1-216-017-91 RES-CHIP 47 5% 1/10W (EXCEPT NS51P/NS15) R424 1-216-025-91 RES-CHIP 100 5% 1/10W (NS15 ONLY) R425 1-216-025-91 RES-CHIP 100 5% 1/10W (NS15 ONLY) R426 1-216-073-91 RES, CHIP 10K (2012) (EXCEPT NS15) R426 1-216-025-91 RES-CHIP 100 5% 1/10W (NS15 ONLY) R427 1-216-083-91 RES-CHIP 27K 5% 1/10W (EXCEPT NS15) R427 1-216-073-91 RES-CHIP 10K 5% 1/10W (NS15 ONLY) R429 1-216-073-91 RES-CHIP 10K 5% 1/10W (NS15 ONLY) R430 1-216-057-91 RES-CHIP 2.2K 5% 1/10W (NS15 ONLY) R431 1-216-025-91 RES-CHIP 100 5% 1/10W (NS15 ONLY) R432 1-216-025-91 RES-CHIP 100 5% 1/10W (NS15 ONLY) R433 1-216-073-91 RES, CHIP 10K (2012) (EXCEPT NS15) R433 1-216-025-91 RES-CHIP 100 5% 1/10W (NS15 ONLY) R434 1-216-073-91 RES, CHIP 10K (2012) (EXCEPT NS15) R436 1-216-073-91 RES, CHIP 10K (2012) (NS43P/NS53P/NS51P:AUS) R436 1-216-065-91 RES-CHIP 4.7K 5% 1/10W (K56P:SP/NS51P:HK,SP,MY,TW,KR,VN) R436 1-216-057-91 RES-CHIP 2.2K 5% 1/10W (K56P:EA/NS51P:ME2,EA,IR) R436 1-216-081-91 RES-CHIP 22K 5% 1/10W (K56P:RUS/NS51P:ME5,IN) R437 1-216-057-91 RES-CHIP 2.2K 5% 1/10W (NS43P/NS53P/NS51P:AUS) R437 1-216-073-91 RES, CHIP 10K (2012) (K56P:SP,TW/NS51P:HK,SP,MY,TW,KR,VN/NS15) R437 1-216-081-91 RES-CHIP 22K 5% 1/10W (K56P:RUS/NS51P:ME5,IN ) R437 1-216-065-91 RES-CHIP 4.7K 5% 1/10W (NS51P:CN ONLY) R440 1-216-295-91 SHORT CHIP 0 (NS51P ONLY) R440 1-216-073-91 RES-CHIP 10K 5% 1/10W (NS15 ONLY) R441 1-216-295-91 SHORT CHIP 0 (NS51P ONLY) R441 1-216-073-91 RES-CHIP 10K 5% 1/10W (NS15 ONLY) IF-144 IF-145 IF-143 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 8-8 Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark DVP-NS15/NS51P/NS43P/NS53P/K56P R442 1-216-295-91 SHORT CHIP 0 (NS51P ONLY) R442 1-216-073-91 RES-CHIP 10K 5% 1/10W (NS15 ONLY) R444 1-216-027-91 RES-CHIP 120 5% 1/10W (K56P/NS15) R445 1-216-013-91 RES-CHIP 33 5% 1/10W (NS15 ONLY) R446 1-216-065-91 RES-CHIP 4.7K 5% 1/10W (NS15 ONLY) R447 1-216-295-91 SHORT CHIP 0 (NS15 ONLY) R448 1-216-057-91 RES-CHIP 2.2K 5% 1/10W (NS15 ONLY) R450 1-216-069-91 RES-CHIP 6.8K 5% 1/10W (NS15 ONLY) R454 1-216-073-91 RES-CHIP 10K 5% 1/10W (NS15 ONLY) R455 1-216-295-91 SHORT CHIP 0 (NS15 ONLY) R456 1-216-057-91 RES-CHIP 2.2K 5% 1/10W (NS15 ONLY) R457 1-216-073-91 RES-CHIP 10K 5% 1/10W (NS15 ONLY) R458 1-216-049-91 RES-CHIP 1K 5% 1/10W (NS15 ONLY) T401 1-443-906-11 DC-DC CONVERTER TRANSFORMER (K56P/NS51P) X401 1-781-472-21 VIBRATOR, CERAMIC MC-161 MOUNT PWB (K56P) ****************** C501 1-124-257-91 ELECT 2.2UF 20.00% 50V C502 1-115-416-91 CERAMIC CHIP 0.001UF 5.00% 25V C504 1-162-970-91 CERAMIC CHIP 0.01UF 10.00% 25V C505 1-164-390-91 CERAMIC CHIP 330PF 5.00% 50V C508 1-115-416-91 CERAMIC CHIP 0.001UF 5.00% 25V C509 1-162-970-91 CERAMIC CHIP 0.01UF 10.00% 25V C511 1-126-160-11 CAP, ELECT 1.0MF C512 1-162-970-91 CERAMIC CHIP 0.01UF 10.00% 25V C514 1-164-344-91 CERAMIC CHIP 0.068UF 10.00% 25V C515 1-164-004-91 CERAMIC CHIP 0.1UF 10.00% 25V C516 1-164-343-91 CERAMIC CHIP 0.056UF 10.00% 25V C517 1-163-009-91 CAP,CHIP CERAMIC 1000PF B 2012 C518 1-163-019-91 CERAMIC CHIP 0.0068UF 10.00% 50V C519 1-124-589-11 CAP, ELECT 47MF C520 1-163-013-91 CERAMIC CHIP 0.0022UF 10.00% 50V C521 1-163-019-91 CERAMIC CHIP 0.0068UF 10.00% 50V C522 1-164-344-91 CERAMIC CHIP 0.068UF 10.00% 25V C523 1-124-257-91 ELECT 2.2UF 20.00% 50V IF-144 IF-145 IF-143 C524 1-115-340-91 CERAMIC CHIP 0.22UF 10.00% 25V C525 1-115-340-91 CERAMIC CHIP 0.22UF 10.00% 25V C526 1-124-589-11 CAP, ELECT 47MF C527 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V C528 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V C529 1-124-589-11 CAP, ELECT 47MF C530 1-162-970-91 CERAMIC CHIP 0.01UF 10.00% 25V C531 1-162-970-91 CERAMIC CHIP 0.01UF 10.00% 25V C532 1-124-257-91 ELECT 2.2UF 20.00% 50V C533 1-163-251-91 CERAMIC CHIP 100PF 5.00% 50V C535 1-162-970-91 CERAMIC CHIP 0.01UF 10.00% 25V C536 1-162-968-91 CERAMIC CHIP 0.0047UF 10.00% 50V C537 1-162-970-91 CERAMIC CHIP 0.01UF 10.00% 25V C538 1-115-416-91 CERAMIC CHIP 0.001UF 5.00% 25V C539 1-124-589-11 CAP, ELECT 47MF * CN501 1-568-944-11 PIN, CONNECTOR 6P D501 8-719-056-85 DIODE UDZ-TE-17-8.2B D502 8-719-800-76 DIODE 1SS226 D503 8-719-988-61 DIODE 1SS355TE-17 IC501 6-706-025-01 IC HA178L05UA-TL-E IC502 8-759-100-96 IC UPC4558G2 IC503 8-759-100-96 IC UPC4558G2 IC504 8-759-496-41 IC M65850FP-E1 JR501 1-216-295-91 SHORT CHIP 0 JR502 1-216-295-91 SHORT CHIP 0 JR503 1-216-295-91 SHORT CHIP 0 JR504 1-216-295-91 SHORT CHIP 0 JR505 1-216-295-91 SHORT CHIP 0 L501 1-469-561-21 INDUCTOR 100UH Q501 8-729-027-53 TRANSISTOR DTC124TKA-T146 Q502 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX Q503 6-551-287-01 TRANSISTOR 2SD2704K-T146 Q504 8-729-010-05 TRANSISTOR MSB709-RT1 Q505 8-729-424-72 TRANSISTOR UN2217-QRS-TX R501 1-216-097-91 RES-CHIP 100K 5% 1/10W R502 1-216-051-91 RES-CHIP 1.2K 5% 1/10W R503 1-216-049-91 RES-CHIP 1K 5% 1/10W R504 1-216-025-91 RES-CHIP 100 5% 1/10W R505 1-216-085-91 RES, CHIP 33K (2012) MC-161 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 8-9 Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark DVP-NS15/NS51P/NS43P/NS53P/K56P R506 1-216-073-91 RES, CHIP 10K (2012) R507 1-216-061-91 RES, CHIP 3.3K (2012) R508 1-216-049-91 RES-CHIP 1K 5% 1/10W R509 1-216-295-91 SHORT CHIP 0 R510 1-216-089-91 RES, CHIP 47K (2012) R511 1-216-073-91 RES, CHIP 10K (2012) R512 1-216-073-91 RES, CHIP 10K (2012) R514 1-216-073-91 RES, CHIP 10K (2012) R515 1-216-081-91 RES-CHIP 22K 5% 1/10W R516 1-216-081-91 RES-CHIP 22K 5% 1/10W R517 1-216-081-91 RES-CHIP 22K 5% 1/10W R518 1-216-081-91 RES-CHIP 22K 5% 1/10W R519 1-216-097-91 RES-CHIP 100K 5% 1/10W R520 1-216-081-91 RES-CHIP 22K 5% 1/10W R521 1-216-081-91 RES-CHIP 22K 5% 1/10W R522 1-216-049-91 RES-CHIP 1K 5% 1/10W R523 1-216-081-91 RES-CHIP 22K 5% 1/10W R524 1-216-109-91 RES-CHIP 330K 5% 1/10W R526 1-216-073-91 RES, CHIP 10K (2012) R527 1-216-097-91 RES-CHIP 100K 5% 1/10W R529 1-216-063-91 RES-CHIP 3.9K 5% 1/10W R530 1-216-073-91 RES, CHIP 10K (2012) R531 1-216-073-91 RES, CHIP 10K (2012) R532 1-216-081-91 RES-CHIP 22K 5% 1/10W R533 1-216-073-91 RES, CHIP 10K (2012) R534 1-216-073-91 RES, CHIP 10K (2012) R535 1-216-295-91 SHORT CHIP 0 R536 1-216-089-91 RES, CHIP 47K (2012) R537 1-216-049-91 RES-CHIP 1K 5% 1/10W R538 1-216-073-91 RES, CHIP 10K (2012) RV501 1-227-461-11 CARBON FILM POTENTIOMETER MV A-1168-526-A SERVICE ASSY, MV (NS15) A-1168-959-A SERVICE ASSY, MV (NS51P: HK,SP,MY,KR,TW) A-1169-005-A SERVICE ASSY, MV (NS51P: ME2,EA,IR) A-1169-221-A SERVICE ASSY, MV (NS51P: CH) A-1169-024-A SERVICE ASSY, MV (NS51P: ME5,IN) A-1169-011-A SERVICE ASSY, MV (NS51P: AUS) A-1158-440-A SERVICE ASSY, MV (NS53P: MX) A-1158-441-A SERVICE ASSY, MV (NS53P: E) A-1158-299-A SERVICE ASSY, MV (NS53P: AR) A-1158-297-A SERVICE ASSY, MV (NS53P: BR) A-1158-300-A SERVICE ASSY, MV (NS43P: AR) A-1158-298-A SERVICE ASSY, MV (NS43P: BR) A-1164-608-A SERVICE ASSY, MV (K56P: SP,TW) A-1164-615-A SERVICE ASSY, MV (K56P: EA) A-1164-990-A SERVICE ASSY, MV (K56P: RUS) A-1169-457-A SERVICE ASSY, MV (NS51P:VN) ***************** C101 1-162-970-91 CERAMIC CHIP 0.01UF 10.00% 25V C102 1-107-826-91 CERAMIC CHIP 0.1UF 10.00% 16V C103 1-162-970-91 CERAMIC CHIP 0.01UF 10.00% 25V C105 1-126-786-91 ELECT 47UF 20% 16V C106 1-162-970-91 CERAMIC CHIP 0.01UF 10.00% 25V C108 1-162-965-91 CERAMIC CHIP 0.0015UF 10.00% 50V C109 1-162-970-91 CERAMIC CHIP 0.01UF 10.00% 25V C111 1-126-964-91 ELECT 10UF 20.00% 50V C112 1-126-786-91 ELECT 47UF 20% 16V C113 1-162-970-91 CERAMIC CHIP 0.01UF 10.00% 25V C114 1-107-826-91 CERAMIC CHIP 0.1UF 10.00% 16V C115 1-107-826-91 CERAMIC CHIP 0.1UF 10.00% 16V C116 1-107-826-91 CERAMIC CHIP 0.1UF 10.00% 16V C117 1-126-964-91 ELECT 10UF 20.00% 50V C118 1-126-964-91 ELECT 10UF 20.00% 50V C119 1-126-964-91 ELECT 10UF 20.00% 50V C120 1-165-908-91 CERAMIC CHIP 1UF 10% 10V C121 1-165-908-91 CERAMIC CHIP 1UF 10% 10V C122 1-165-908-91 CERAMIC CHIP 1UF 10% 10V C123 1-165-908-91 CERAMIC CHIP 1UF 10% 10V C124 1-165-908-91 CERAMIC CHIP 1UF 10% 10V C125 1-107-826-91 CERAMIC CHIP 0.1UF 10.00% 16V C126 1-107-826-91 CERAMIC CHIP 0.1UF 10.00% 16V C130 1-107-826-91 CERAMIC CHIP 0.1UF 10.00% 16V C131 1-125-889-91 CERAMIC CHIP 2.2UF 10% 10V C132 1-107-826-91 CERAMIC CHIP 0.1UF 10.00% 16V C133 1-107-826-91 CERAMIC CHIP 0.1UF 10.00% 16V C135 1-164-677-91 CERAMIC CHIP 0.033UF 10.00% 16V C136 1-162-970-91 CERAMIC CHIP 0.01UF 10.00% 25V C137 1-107-826-91 CERAMIC CHIP 0.1UF 10.00% 16V C138 1-162-964-91 CERAMIC CHIP 0.001UF 10.00% 50V C139 1-162-919-91 CERAMIC CHIP 22PF 5.00% 50V C140 1-107-826-91 CERAMIC CHIP 0.1UF 10.00% 16V C144 1-162-970-91 CERAMIC CHIP 0.01UF 10.00% 25V C146 1-107-826-91 CERAMIC CHIP 0.1UF 10.00% 16V C147 1-165-176-91 CERAMIC CHIP 0.047UF 10.00% 16V C148 1-165-176-91 CERAMIC CHIP 0.047UF 10.00% 16V C149 1-107-826-91 CERAMIC CHIP 0.1UF 10.00% 16V C150 1-126-964-91 ELECT 10UF 20.00% 50V C151 1-162-964-91 CERAMIC CHIP 0.001UF 10.00% 50V MC-161 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 8-10 Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark DVP-NS15/NS51P/NS43P/NS53P/K56P MV C152 1-162-916-91 CERAMIC CHIP 12PF 5.00% 50V C153 1-162-917-91 CERAMIC CHIP 15PF 5.00% 50V C154 1-107-826-91 CERAMIC CHIP 0.1UF 10.00% 16V C155 1-162-970-91 CERAMIC CHIP 0.01UF 10.00% 25V C156 1-162-970-91 CERAMIC CHIP 0.01UF 10.00% 25V C158 1-162-970-91 CERAMIC CHIP 0.01UF 10.00% 25V C160 1-162-970-91 CERAMIC CHIP 0.01UF 10.00% 25V C162 1-162-970-91 CERAMIC CHIP 0.01UF 10.00% 25V C163 1-162-970-91 CERAMIC CHIP 0.01UF 10.00% 25V C164 1-162-970-91 CERAMIC CHIP 0.01UF 10.00% 25V C169 1-107-826-91 CERAMIC CHIP 0.1UF 10.00% 16V C172 1-162-970-91 CERAMIC CHIP 0.01UF 10.00% 25V C174 1-162-970-91 CERAMIC CHIP 0.01UF 10.00% 25V C175 1-162-970-91 CERAMIC CHIP 0.01UF 10.00% 25V C176 1-162-970-91 CERAMIC CHIP 0.01UF 10.00% 25V C177 1-126-947-11 CAP, ELECT 47MF C179 1-107-826-91 CERAMIC CHIP 0.1UF 10.00% 16V C180 1-107-826-91 CERAMIC CHIP 0.1UF 10.00% 16V C181 1-107-826-91 CERAMIC CHIP 0.1UF 10.00% 16V C182 1-127-715-91 CERAMIC CHIP 0.22UF 10% 16V C183 1-128-934-91 CERAMIC CHIP 0.33UF 20% 10V C184 1-162-970-91 CERAMIC CHIP 0.01UF 10.00% 25V C186 1-127-715-91 CERAMIC CHIP 0.22UF 10% 16V C187 1-126-947-11 CAP, ELECT 47MF C188 1-165-908-91 CERAMIC CHIP 1UF 10% 10V C189 1-107-826-91 CERAMIC CHIP 0.1UF 10.00% 16V C190 1-126-947-11 CAP, ELECT 47MF C191 1-107-826-91 CERAMIC CHIP 0.1UF 10.00% 16V C192 1-162-970-91 CERAMIC CHIP 0.01UF 10.00% 25V C193 1-127-715-91 CERAMIC CHIP 0.22UF 10% 16V C195 1-127-715-91 CERAMIC CHIP 0.22UF 10% 16V C197 1-107-826-91 CERAMIC CHIP 0.1UF 10.00% 16V C199 1-162-968-91 CERAMIC CHIP 0.0047UF 10.00% 50V C203 1-162-970-91 CERAMIC CHIP 0.01UF 10.00% 25V C205 1-164-230-91 CERAMIC CHIP 220PF 5.00% 50V C206 1-164-230-91 CERAMIC CHIP 220PF 5.00% 50V C208 1-162-970-91 CERAMIC CHIP 0.01UF 10.00% 25V C209 1-164-677-91 CERAMIC CHIP 0.033UF 10.00% 16V C210 1-162-970-91 CERAMIC CHIP 0.01UF 10.00% 25V C211 1-164-677-91 CERAMIC CHIP 0.033UF 10.00% 16V C212 1-162-970-91 CERAMIC CHIP 0.01UF 10.00% 25V C213 1-162-970-91 CERAMIC CHIP 0.01UF 10.00% 25V C214 1-162-964-91 CERAMIC CHIP 0.001UF 10.00% 50V C216 1-107-826-91 CERAMIC CHIP 0.1UF 10.00% 16V C217 1-126-947-11 CAP, ELECT 47MF C218 1-126-964-91 ELECT 10UF 20.00% 50V C219 1-162-970-91 CERAMIC CHIP 0.01UF 10.00% 25V C220 1-126-964-91 ELECT 10UF 20.00% 50V C221 1-107-826-91 CERAMIC CHIP 0.1UF 10.00% 16V C222 1-107-826-91 CERAMIC CHIP 0.1UF 10.00% 16V C223 1-107-826-91 CERAMIC CHIP 0.1UF 10.00% 16V C224 1-162-970-91 CERAMIC CHIP 0.01UF 10.00% 25V C225 1-162-964-91 CERAMIC CHIP 0.001UF 10.00% 50V C226 1-162-964-91 CERAMIC CHIP 0.001UF 10.00% 50V C228 1-162-968-91 CERAMIC CHIP 0.0047UF 10.00% 50V C301 1-107-826-91 CERAMIC CHIP 0.1UF 10.00% 16V C303 1-162-970-91 CERAMIC CHIP 0.01UF 10.00% 25V (NS15 ONLY) C304 1-162-970-91 CERAMIC CHIP 0.01UF 10.00% 25V (NS15 ONLY) C305 1-126-947-11 CAP, ELECT 47MF (NS15 ONLY) C307 1-126-947-11 CAP, ELECT 47MF (NS15 ONLY) C310 1-126-786-91 ELECT 47UF 20% 16V C311 1-107-826-91 CERAMIC CHIP 0.1UF 10.00% 16V (EXCEPT NS15) C311 1-127-715-91 CERAMIC CHIP 0.22UF 10% 16V (NS15 ONLY) C312 1-107-826-91 CERAMIC CHIP 0.1UF 10.00% 16V (EXCEPT NS15) C313 1-126-786-91 ELECT 47UF 20% 16V C314 1-107-826-91 CERAMIC CHIP 0.1UF 10.00% 16V (EXCEPT NS15) C314 1-127-715-91 CERAMIC CHIP 0.22UF 10% 16V (NS15 ONLY) C315 1-162-927-91 CERAMIC CHIP 100PF 5.00% 50V (NS15 ONLY) C316 1-162-927-91 CERAMIC CHIP 100PF 5.00% 50V C317 1-162-927-91 CERAMIC CHIP 100PF 5.00% 50V C318 1-162-927-91 CERAMIC CHIP 100PF 5.00% 50V (NS15 ONLY) C401 1-115-416-91 CERAMIC CHIP 0.001UF 5.00% 25V (NS15/NS51P/NS53P/NS43P) C401 1-164-390-91 CERAMIC CHIP 330PF 5.00% 50V (K56P ONLY) C402 1-115-416-91 CERAMIC CHIP 0.001UF 5.00% 25V (NS15/NS51P/NS43P/NS53P) C402 1-164-390-91 CERAMIC CHIP 330PF 5.00% 50V (K56P ONLY) C403 1-164-315-91 CERAMIC CHIP 470PF 5.00% 50V (K56P ONLY) C404 1-164-315-91 CERAMIC CHIP 470PF 5.00% 50V (K56P ONLY) C405 1-162-927-91 CERAMIC CHIP 100PF 5.00% 50V (NS15/NS51P/NS43P/ NS53P) C406 1-162-927-91 CERAMIC CHIP 100PF 5.00% 50V (EXCEPT K56P) C407 1-162-970-91 CERAMIC CHIP 0.01UF 10.00% 25V C408 1-162-970-91 CERAMIC CHIP 0.01UF 10.00% 25V C409 1-126-960-91 ELECT 1UF 20.00% 50V C410 1-126-947-11 CAP, ELECT 47MF C411 1-126-947-11 CAP, ELECT 47MF (NS15/NS51P/NS43P/NS53P) C411 1-104-660-91 CAP, ELECT 47MF (K56P ONLY) C412 1-126-960-91 ELECT 1UF 20.00% 50V (K56P ONLY) C413 1-126-934-91 ELECT 220UF 20.00% 16V C414 1-162-927-91 CERAMIC CHIP 100PF 5.00% 50V (K56P ONLY) C415 1-164-230-91 CERAMIC CHIP 220PF 5.00% 50V C416 1-164-230-91 CERAMIC CHIP 220PF 5.00% 50V C419 1-162-927-91 CERAMIC CHIP 100PF 5.00% 50V (K56P ONLY) C420 1-162-970-91 CERAMIC CHIP 0.01UF 10.00% 25V (K56P ONLY) C421 1-162-970-91 CERAMIC CHIP 0.01UF 10.00% 25V C423 1-126-964-91 ELECT 10UF 20.00% 50V C424 1-126-964-91 ELECT 10UF 20.00% 50V www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 8-11 Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark DVP-NS15/NS51P/NS43P/NS53P/K56P MV C425 1-162-970-91 CERAMIC CHIP 0.01UF 10.00% 25V (EXCEPT NS43P/NS53P:MX,E/NS15) C427 1-126-947-11 CAP, ELECT 47MF 16V (EXCEPT 43P: AR,BR/NS53P:MX,E/NS15) C428 1-126-964-91 ELECT 10UF 20.00% 50V C429 1-126-964-91 ELECT 10UF 20.00% 50V C430 1-162-970-91 CERAMIC CHIP 0.01UF 10.00% 25V (K56P ONLY) C431 1-126-947-11 CAP, ELECT 47MF (K56P ONLY) C444 1-126-947-11 CAP, ELECT 47MF C445 1-163-251-91 CERAMIC CHIP 100PF 5.00% 50V (K56P ONLY) C446 1-163-251-91 CERAMIC CHIP 100PF 5.00% 50V (K56P ONLY) C447 1-163-251-91 CERAMIC CHIP 100PF 5.00% 50V (K56P ONLY) C501 1-107-826-91 CERAMIC CHIP 0.1UF 10.00% 16V C502 1-126-786-91 ELECT 47UF 20% 16V C503 1-126-786-91 ELECT 47UF 20% 16V C504 1-126-786-91 ELECT 47UF 20% 16V C508 1-107-826-91 CERAMIC CHIP 0.1UF 10.00% 16V C510 1-107-826-91 CERAMIC CHIP 0.1UF 10.00% 16V C512 1-107-826-91 CERAMIC CHIP 0.1UF 10.00% 16V (NS15/NS51P/K56P) C513 1-107-826-91 CERAMIC CHIP 0.1UF 10.00% 16V C514 1-126-786-91 ELECT 47UF 20% 16V * CN105 1-564-708-11 PIN, CONNECTOR (SMALL TYPE) 6P * CN201 1-564-708-11 PIN, CONNECTOR (SMALL TYPE) 6P CN202 1-815-381-11 CONNECTOR, FPC/FFC 5P CN404 1-568-783-11 PIN, CONNECTOR 6P (K56P ONLY) * CN501 1-564-009-11 PIN, CONNECTOR 10P D301 8-719-050-37 DIODE M1MA152WA-T1 (NS15 ONLY) D302 8-719-988-61 DIODE 1SS355TE-17 (NS15 ONLY) D303 8-719-071-15 DIODE HZM6.8ZWA1TL (NS15 ONLY) D304 8-719-071-15 DIODE HZM6.8ZWA1TL (NS15 ONLY) D305 8-719-071-15 DIODE HZM6.8ZWA1TL (NS15 ONLY) D306 8-719-071-15 DIODE HZM6.8ZWA1TL (NS15 ONLY) D308 8-719-071-15 DIODE HZM6.8ZWA1TL (NS15 ONLY) D309 8-719-069-56 DIODE UDZSTE-176.2B (NS15 ONLY) D309 8-719-071-15 DIODE HZM6.8ZWA1TL (NS43P/DVP-NS53PK56P) D310 8-719-988-61 DIODE 1SS355TE-17 (EXCEPT NS15) D310 8-719-083-63 DIODE UDZSTE-1713B (NS15 ONLY) D401 8-719-914-43 DIODE DAN202K D402 8-719-914-44 DIODE DAP202K D404 8-719-988-61 DIODE 1SS355TE-17 D405 8-719-988-61 DIODE 1SS355TE-17 (K56P ONLY) FB106 1-469-324-21 FERRITE 0UH FB107 1-469-324-21 FERRITE 0UH FB108 1-469-324-21 FERRITE 0UH FB115 1-469-670-21 FERRITE 0UH IC102 6-806-220-01 IC S99-50068E-10GBPXXXXA (NS51P:KR,TW,HK,SP,MY,VN,CH) IC102 6-806-221-01 IC S99-50068E-10GBPXXXXE (NS51P:ME,EA,IR,IN,AUS) * IC102 6-806-219-01 IC S99-50068E-10GBPXXXXU (NS43P/NS53P:AR,BR) IC102 6-806-229-01 IC S99-50068E-10GEBXXXXE (NS15) IC102 6-806-449-01 IC S99-50068E-10GSKXXXXA (K56P:SP,TW,EA) IC102 6-806-795-01 IC MR27V1602F-318TN (NS53P:E,MX) IC103 SEE NOTE IC105 6-702-302-01 IC TK11133CSCL-G IC107 6-702-302-01 IC TK11133CSCL-G IC110 6-707-739-01 IC MM1661JTRE IC201 6-704-524-01 IC FAN8036L IC303 8-759-667-17 IC L79M05TLL-SONY-TL-E IC304 6-705-924-01 IC LA73052-TLM-E (NS15 ONLY) IC304 6-706-453-01 IC NJM2587V(TE2) (NS43/NS51P/NS53P/K56P) IC401 8-759-100-96 IC UPC4558G2 IC402 8-759-100-96 IC UPC4558G2 (K56P ONLY) JS401 1-216-295-91 SHORT CHIP 0 JS402 1-216-295-91 SHORT CHIP 0 (K56P ONLY) JS403 1-216-295-91 SHORT CHIP 0 (K56P ONLY) *PS501 1-576-892-11 FUSE 1A 32V *PS502 1-576-892-11 FUSE 1A 32V Q101 6-550-008-01 TRANSISTOR UM6K1N-TN Q102 6-550-653-01 TRANSISTOR QST8TR Q103 8-729-424-63 TRANSISTOR UN2212-TX Q301 8-729-024-89 TRANSISTOR MUN2213T1 (NS15: AEP,UK) Q302 8-729-024-89 TRANSISTOR MUN2213T1 (NS15 ONLY) Q303 8-729-024-83 TRANSISTOR MUN2111T1 (NS15 ONLY) Q304 8-729-024-89 TRANSISTOR MUN2213T1 Q305 8-729-024-83 TRANSISTOR MUN2111T1 Q306 8-729-024-87 TRANSISTOR MUN2211T1 (NS15 ONLY) Q306 8-729-024-89 TRANSISTOR MUN2213T1 (NS43P/NS53P/NS51P/K56P) Note : The components identified by mark or dotted line with mark are critical for safety. Replace only with part number specified. Notes: MV-47/MV-48 mounted PWB must be replaced if IC103 (EEPROM IC) is damaged or not functioning. The old MV-47/MV-48 mounted PWB must be completely disposed. IC405 6-600-430-01 IC TOTX177(F,T) (EXCEPT NS15/NS43P:BR,AR/NS53P:MX,E) IC108 6-703-224-01 IC S-80828CNNB-B8NT2G IC102 6-806-450-01 IC S99-50068E-10GSKXXXXE (K56P:RUS) IC101 6-709-351-01 IC CXD9197R IC104 6-707-897-01 IC EDS6416AHTA-75-E www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 8-12 Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark DVP-NS15/NS51P/NS43P/NS53P/K56P Q371 6-550-840-01 TRANSISTOR 2SC2712-YGR-TE85L (NS15 ONLY) Q372 6-550-841-01 TRANSISTOR 2SA1162-YGR-TE85L (NS15 ONLY) Q401 8-729-010-10 TRANSISTOR MSB710-RT1 Q402 8-729-024-89 TRANSISTOR MUN2213T1 Q403 8-729-010-25 TRANSISTOR MSD601-RT1 Q404 8-729-424-72 TRANSISTOR UN2217-QRS-TX Q405 8-729-010-05 TRANSISTOR MSB709-RT1 Q406 8-729-024-89 TRANSISTOR MUN2213T1 (K56P ONLY) Q407 6-551-287-01 TRANSISTOR 2SD2704K-T146 Q408 6-551-287-01 TRANSISTOR 2SD2704K-T146 Q409 8-729-424-72 TRANSISTOR UN2217-QRS-TX (K56P ONLY) Q410 8-729-010-05 TRANSISTOR MSB709-RT1 (K56P ONLY) Q411 8-729-010-25 TRANSISTOR MSD601-RT1 Q412 6-551-287-01 TRANSISTOR 2SD2704K-T146 Q413 6-551-287-01 TRANSISTOR 2SD2704K-T146 Q414 6-551-287-01 TRANSISTOR 2SD2704K-T146 (K56P ONLY) Q416 8-729-010-05 TRANSISTOR MSB709-RT1 Q417 8-729-024-89 TRANSISTOR MUN2213T1 (K56P ONLY) Q501 6-551-458-01 TRANSISTOR KTD1624-B Q502 8-729-024-86 TRANSISTOR MUN2114T1 R101 1-216-809-91 METAL CHIP 100 5% 1/10W R102 1-216-295-71 SHORT CHIP 0 R106 1-216-833-91 METAL CHIP 10K 5% 1/10W R107 1-216-833-91 METAL CHIP 10K 5% 1/10W R108 1-216-857-91 METAL CHIP 1M 5% 1/10W R109 1-216-864-91 SHORT CHIP 0 R110 1-216-841-91 METAL CHIP 47K 5% 1/10W R111 1-216-809-91 METAL CHIP 100 5% 1/10W R112 1-211-977-91 METAL CHIP 22 0.5% 1/10W R113 1-211-977-91 METAL CHIP 22 0.5% 1/10W R114 1-216-845-91 METAL CHIP 100K 5% 1/10W R115 1-211-977-91 METAL CHIP 22 0.5% 1/10W R116 1-216-821-91 METAL CHIP 1K 5% 1/10W R117 1-216-841-91 METAL CHIP 47K 5% 1/10W R118 1-216-801-91 METAL CHIP 22 5% 1/10W R119 1-216-295-91 SHORT CHIP 0 R120 1-216-801-91 METAL CHIP 22 5% 1/10W R121 1-216-801-91 METAL CHIP 22 5% 1/10W R122 1-216-864-91 SHORT CHIP 0 R123 1-216-864-91 SHORT CHIP 0 R124 1-216-841-91 METAL CHIP 47K 5% 1/10W R126 1-216-864-91 SHORT CHIP 0 (NS15/NS51P/NS43P/NS53P/K56P) R127 1-216-864-91 SHORT CHIP 0 (NS15/NS51P) R129 1-216-295-91 SHORT CHIP 0 R132 1-216-845-91 METAL CHIP 100K 5% 1/10W R134 1-216-864-91 SHORT CHIP 0 R135 1-216-821-91 METAL CHIP 1K 5% 1/10W R136 1-216-835-91 METAL CHIP 15K 5% 1/10W R137 1-216-864-91 SHORT CHIP 0 R141 1-216-855-91 METAL CHIP 680K 5% 1/10W R142 1-216-845-91 METAL CHIP 100K 5% 1/10W R143 1-216-864-91 SHORT CHIP 0 R144 1-216-864-91 SHORT CHIP 0 (NS15 ONLY) R145 1-216-864-91 SHORT CHIP 0 R147 1-216-864-91 SHORT CHIP 0 R148 1-216-864-91 SHORT CHIP 0 R149 1-216-864-91 SHORT CHIP 0 R152 1-216-864-91 SHORT CHIP 0 R153 1-216-864-91 SHORT CHIP 0 R154 1-216-864-91 SHORT CHIP 0 R155 1-216-864-91 SHORT CHIP 0 R156 1-216-809-91 METAL CHIP 100 5% 1/10W R159 1-216-864-91 SHORT CHIP 0 (K56P ONLY) R160 1-216-864-91 SHORT CHIP 0 (NS15/K56P) R164 1-216-864-91 SHORT CHIP 0 R181 1-216-864-91 SHORT CHIP 0 (NS15 ONLY) R183 1-216-864-91 SHORT CHIP 0 R184 1-216-864-91 SHORT CHIP 0 (K56P ONLY) R185 1-216-864-91 SHORT CHIP 0 R191 1-216-821-91 METAL CHIP 1K 5% 1/10W R192 1-218-827-91 METAL CHIP 150 0.5% 1/10W R193 1-216-821-91 METAL CHIP 1K 5% 1/10W R195 1-218-827-91 METAL CHIP 150 0.5% 1/10W R196 1-216-827-91 METAL CHIP 3.3K 5% 1/10W (K56P ONLY) R197 1-218-827-91 METAL CHIP 150 0.5% 1/10W R204 1-216-822-91 METAL CHIP 1.2K 5% 1/10W R205 1-216-833-91 METAL CHIP 10K 5% 1/10W R206 1-216-833-91 METAL CHIP 10K 5% 1/10W R207 1-216-826-91 METAL CHIP 2.7K 5% 1/10W R208 1-216-839-91 METAL CHIP 33K 5% 1/10W R209 1-216-839-91 METAL CHIP 33K 5% 1/10W R210 1-216-841-91 METAL CHIP 47K 5% 1/10W R212 1-216-833-91 METAL CHIP 10K 5% 1/10W R213 1-218-867-11 RES, CHIP 6.8K (1608) R214 1-216-835-91 METAL CHIP 15K 5% 1/10W R215 1-216-834-91 METAL CHIP 12K 5% 1/10W R216 1-216-834-91 METAL CHIP 12K 5% 1/10W R219 1-216-838-91 METAL CHIP 27K 5% 1/10W R220 1-216-833-91 METAL CHIP 10K 5% 1/10W R221 1-218-889-91 METAL CHIP 56K 0.5% 1/10W R222 1-216-839-91 METAL CHIP 33K 5% 1/10W R223 1-218-895-91 METAL CHIP 100K 0.5% 1/10W R224 1-216-833-91 METAL CHIP 10K 5% 1/10W R225 1-218-895-91 METAL CHIP 100K 0.5% 1/10W R226 1-218-889-91 METAL CHIP 56K 0.5% 1/10W R227 1-216-864-91 SHORT CHIP 0 R228 1-216-864-91 SHORT CHIP 0 (NS53P/NS43P/K56P) R230 1-218-893-91 METAL CHIP 82K 0.5% 1/10W R231 1-218-875-91 METAL CHIP 15K 0.5% 1/10W R232 1-218-877-91 METAL CHIP 18K 0.5% 1/10W R233 1-218-883-91 METAL CHIP 33K 0.5% 1/10W R234 1-216-833-91 METAL CHIP 10K 5% 1/10W R235 1-216-864-91 SHORT CHIP 0 R236 1-216-821-91 METAL CHIP 1K 5% 1/10W R237 1-216-821-91 METAL CHIP 1K 5% 1/10W R238 1-216-829-91 METAL CHIP 4.7K 5% 1/10W R239 1-216-829-91 METAL CHIP 4.7K 5% 1/10W R243 1-216-809-91 METAL CHIP 100 5% 1/10W R246 1-216-829-91 METAL CHIP 4.7K 5% 1/10W MV www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 8-13 Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark DVP-NS15/NS51P/NS43P/NS53P/K56P R247 1-216-821-91 METAL CHIP 1K 5% 1/10W R248 1-216-864-91 SHORT CHIP 0 R249 1-216-864-91 SHORT CHIP 0 R250 1-216-864-91 SHORT CHIP 0 R251 1-216-864-91 SHORT CHIP 0 R301 1-216-081-91 RES-CHIP 22K 5% 1/10W (NS15 ONLY) R304 1-216-055-91 RES-CHIP 1.8K 5% 1/10W (NS15 ONLY) R305 1-216-295-91 SHORT CHIP 0 (NS15 ONLY) R306 1-216-105-91 RES-CHIP 220K 5% 1/10W (NS15 ONLY) R309 1-216-037-91 RES-CHIP 330 5% 1/10W (NS15 ONLY) R310 1-216-037-91 RES-CHIP 330 5% 1/10W (NS15 ONLY) R311 1-216-037-91 RES-CHIP 330 5% 1/10W (NS15 ONLY) R312 1-216-037-91 RES-CHIP 330 5% 1/10W (NS15 ONLY) R313 1-216-295-91 SHORT CHIP 0 NS15 ONLY) R316 1-216-051-91 RES-CHIP 1.2K 5% 1/10W (NS15 ONLY) R317 1-216-033-91 RES-CHIP 220 5% 1/10W (NS15 ONLY) R318 1-216-033-91 RES-CHIP 220 5% 1/10W (NS15 ONLY) R319 1-216-051-91 RES-CHIP 1.2K 5% 1/10W (NS15 ONLY) R320 1-216-295-91 SHORT CHIP 0 (NS15 ONLY) R321 1-216-051-91 RES-CHIP 1.2K 5% 1/10W EXCEPT (NS15) R321 1-216-833-91 METAL CHIP 10K 5% 1/10W R323 1-216-295-91 SHORT CHIP 0 (NS15 ONLY ) R323 1-216-833-91 METAL CHIP 10K 5% 1/10W EXCEPT (NS15 ONLY) R324 1-216-833-91 METAL CHIP 10K 5% 1/10W EXCEPT (NS15 ONLY) R326 1-216-041-91 RES-CHIP 470 5% 1/10W (NS15 ONLY) R327 1-216-041-91 RES-CHIP 470 5% 1/10W (NS15 ONLY) R327 1-216-833-91 METAL CHIP 10K 5% 1/10W EXCEPT (NS15 ONLY) R331 1-211-990-91 METAL CHIP 75 0.5% 1/10W R332 1-211-990-91 METAL CHIP 75 0.5% 1/10W R333 1-211-990-91 METAL CHIP 75 0.5% 1/10W R334 1-211-990-91 METAL CHIP 75 0.5% 1/10W R335 1-211-990-91 METAL CHIP 75 0.5% 1/10W (NS43P/NS53P/NS51P/K56P) R336 1-216-017-91 RES-CHIP 47 5% 1/10W (NS15 ONLY) R336 1-211-990-91 METAL CHIP 75 0.5% 1/10W EXCEPT (NS15 ONLY) R340 1-216-295-91 SHORT CHIP 0 (NS15 ONLY) R341 1-216-295-91 SHORT CHIP 0 (NS15 ONLY) R342 1-216-295-91 SHORT CHIP 0 (NS15 ONLY) R343 1-216-295-91 SHORT CHIP 0 (NS15 ONLY) R344 1-216-295-91 SHORT CHIP 0 (NS15 ONLY) R345 1-216-295-91 SHORT CHIP 0 (NS15 ONLY) R346 1-216-295-91 SHORT CHIP 0 (NS15 ONLY) R372 1-216-809-91 METAL CHIP 100 5% 1/10W (NS15 ONLY) R373 1-216-821-91 METAL CHIP 1K 5% 1/10W (NS15 ONLY) R374 1-216-809-91 METAL CHIP 100 5% 1/10W (NS15 ONLY) R375 1-216-864-91 SHORT CHIP 0 (EXCEPT NS15) R376 1-216-821-91 METAL CHIP 1K 5% 1/10W (NS15 ONLY ) R377 1-216-864-91 SHORT CHIP 0 R382 1-216-864-91 SHORT CHIP 0 R398 1-216-295-91 SHORT CHIP 0 (EXCEPT NS15) R399 1-216-295-91 SHORT CHIP 0 (EXCEPT NS15) R401 1-208-799-91 METAL CHIP 5.1K 0.5% 1/10W (EXCEPT K56P) R402 1-216-845-91 METAL CHIP 100K 5% 1/10W R403 1-216-295-91 SHORT CHIP 0 R404 1-208-799-91 METAL CHIP 5.1K 0.5% 1/10W (NS15/NS51P/NS43P/NS53P) R405 1-216-295-91 SHORT CHIP 0 (EXCEPT K56P) R406 1-216-295-91 SHORT CHIP 0 (EXCEPT K56P) R407 1-218-875-91 METAL CHIP 15K 0.5% 1/10W (K56P: ONLY) R408 1-218-875-91 METAL CHIP 15K 0.5% 1/10W (K56P ONLY) R409 1-208-799-91 METAL CHIP 5.1K 0.5% 1/10W (NS15/NS51P/NS43P/NS53P) R409 1-208-796-91 METAL CHIP 3.9K 0.5% 1/10W (-K56P ONLY) R410 1-208-799-91 METAL CHIP 5.1K 0.5% 1/10W (NS15/NS51P/NS43PNS53P ) R410 1-208-796-91 METAL CHIP 3.9K 0.5% 1/10W (K56P ONLY) R411 1-216-085-91 RES, CHIP 33K (2012) (NS15/NS51P/NS43P/NS53P) R411 1-216-295-91 RES, CHIP 0 (K56P ONLY) R412 1-216-085-91 RES, CHIP 33K (2012) (EXCEPT K56P) R412 1-216-295-91 SHORT CHIP 0 (K56P ONLY) R413 1-216-829-91 METAL CHIP 4.7K 5% 1/10W R415 1-216-864-91 SHORT CHIP 0 (K56P ONLY) R416 1-216-830-91 METAL CHIP 5.6K 5% 1/10W R417 1-216-833-91 METAL CHIP 10K 5% 1/10W R418 1-216-845-91 METAL CHIP 100K 5% 1/10W R419 1-216-849-91 METAL CHIP 220K 5% 1/10W R420 1-216-817-91 METAL CHIP 470 5% 1/10W R421 1-216-833-91 METAL CHIP 10K 5% 1/10W R422 1-216-833-91 METAL CHIP 10K 5% 1/10W MV www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 8-14 Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark DVP-NS15/NS51P/NS43P/NS53P/K56P R424 1-216-833-91 METAL CHIP 10K 5% 1/10W R425 1-216-841-91 METAL CHIP 47K 5% 1/10W R426 1-216-817-91 METAL CHIP 470 5% 1/10W R427 1-216-817-91 METAL CHIP 470 5% 1/10W R428 1-216-833-91 METAL CHIP 10K 5% 1/10W R429 1-216-841-91 METAL CHIP 47K 5% 1/10W R430 1-216-841-91 METAL CHIP 47K 5% 1/10W R431 1-216-833-91 METAL CHIP 10K 5% 1/10W (K56P ONLY) R432 1-216-833-91 METAL CHIP 10K 5% 1/10W (K56P ONLY) R433 1-216-841-91 METAL CHIP 47K 5% 1/10W (K56P ONLY) R434 1-216-829-91 METAL CHIP 4.7K 5% 1/10W R436 1-216-833-91 METAL CHIP 10K 5% 1/10W (K56P ONLY) R435 1-216-829-91 METAL CHIP 4.7K 5% 1/10W R438 1-216-845-91 METAL CHIP 100K 5% 1/10W R439 1-216-845-91 METAL CHIP 100K 5% 1/10W (K56P ONLY) R440 1-216-817-91 METAL CHIP 470 5% 1/10W (EXCEPT NS15) R441 1-216-817-91 METAL CHIP 470 5% 1/10W (EXCEPT NS15) R442 1-216-864-91 SHORT CHIP 0 (EXCEPT NS15/K56P) R443 1-216-864-91 SHORT CHIP 0 (EXCEPT NS15/K56P) R445 1-208-799-91 METAL CHIP 5.1K 0.5% 1/10W (NS15/NS51P/NS43P/NS53P) R445 1-208-799-91 METAL CHIP 5.1K 0.5% 1/10W (EXCEPT K56P) R445 1-208-796-91 METAL CHIP 3.9K 0.5% 1/10W (K56P ONLY) R446 1-208-799-91 METAL CHIP 5.1K 0.5% 1/10W (NS15/NS51P/NS43P/NS53P) R446 1-208-796-91 METAL CHIP 3.9K 0.5% 1/10W (K56P ONLY) R448 1-216-833-91 METAL CHIP 10K 5% 1/10W (K56P ONLY) R449 1-216-813-91 METAL CHIP 220 5% 1/10W R450 1-216-833-91 METAL CHIP 10K 5% 1/10W (K56P ONLY) R451 1-216-807-91 METAL CHIP 68 5% 1/10W R452 1-216-833-91 METAL CHIP 10K 5% 1/10W R453 1-216-821-91 METAL CHIP 1K 5% 1/10W R454 1-216-821-91 METAL CHIP 1K 5% 1/10W R455 1-216-833-91 METAL CHIP 10K 5% 1/10W (K56P ONLY) R456 1-216-821-91 METAL CHIP 1K 5% 1/10W R457 1-216-833-91 METAL CHIP 10K 5% 1/10W (K56P ONLY) R458 1-216-833-91 METAL CHIP 10K 5% 1/10W R459 1-216-833-91 METAL CHIP 10K 5% 1/10W (K56P ONLY) R460 1-216-841-91 METAL CHIP 47K 5% 1/10W (K56P ONLY) R461 1-216-817-91 METAL CHIP 470 5% 1/10W (K56P ONLY) R462 1-216-833-91 METAL CHIP 10K 5% 1/10W (K56P ONLY) R463 1-216-864-91 SHORT CHIP 0 (K56P ONLY) R464 1-208-796-91 METAL CHIP 3.9K 0.5% 1/10W (K56P ONLY) R467 1-208-796-91 METAL CHIP 3.9K 0.5% 1/10W (K56P ONLY) R469 1-218-853-91 METAL CHIP 1.8K 0.5% 1/10W (K56P ONLY) R470 1-218-853-91 METAL CHIP 1.8K 0.5% 1/10W (K56P ONLY) R471 1-216-821-91 METAL CHIP 1K 5% 1/10W (K56P ONLY) R477 1-216-833-91 METAL CHIP 10K 5% 1/10W R478 1-216-845-91 METAL CHIP 100K 5% 1/10W (NS15/NS51P/NS43P/NS53P) R479 1-216-833-91 METAL CHIP 10K 5% 1/10W R481 1-216-833-91 METAL CHIP 10K 5% 1/10W R482 1-216-833-91 METAL CHIP 10K 5% 1/10W R484 1-216-830-91 METAL CHIP 5.6K 5% 1/10W R485 1-216-295-91 SHORT CHIP 0 (NS15/NS51P/NS43P/NS53P) R486 1-216-295-91 SHORT CHIP 0 (EXCEPT K56P) R487 1-216-864-91 SHORT CHIP 0 (K56P ONLY) R489 1-216-833-91 METAL CHIP 10K 5% 1/10W R503 1-216-833-91 METAL CHIP 10K 5% 1/10W R504 1-216-827-91 METAL CHIP 3.3K 5% 1/10W R505 1-216-827-91 METAL CHIP 3.3K 5% 1/10W (NS15/NS51P/K56P) R507 1-216-864-91 SHORT CHIP 0 R508 1-216-295-91 SHORT CHIP 0 R509 1-216-295-91 SHORT CHIP 0 R510 1-216-295-91 SHORT CHIP 0 R512 1-216-295-91 SHORT CHIP 0 R513 1-216-295-91 SHORT CHIP 0 R514 1-216-864-91 SHORT CHIP 0 (NS15 ONLY) R516 1-216-295-91 SHORT CHIP 0 R1101 1-218-841-91 METAL CHIP 560 0.5% 1/10W R1102 1-218-827-91 METAL CHIP 150 0.5% 1/10W R1105 1-216-864-91 SHORT CHIP 0 R1107 1-216-864-91 SHORT CHIP 0 R1108 1-216-864-91 SHORT CHIP 0 R1109 1-216-864-91 SHORT CHIP 0 R1110 1-216-826-91 METAL CHIP 2.7K 5% 1/10W R1114 1-216-801-91 METAL CHIP 22 5% 1/10W R1115 1-216-864-91 SHORT CHIP 0 R1118 1-216-821-91 METAL CHIP 1K 5% 1/10W R1119 1-216-864-91 SHORT CHIP 0 R1120 1-216-864-91 SHORT CHIP 0 R1121 1-216-864-91 SHORT CHIP 0 R1122 1-216-864-91 SHORT CHIP 0 R1123 1-216-864-91 SHORT CHIP 0 R1129 1-216-845-91 METAL CHIP 100K 5% 1/10W R1132 1-216-295-71 SHORT CHIP 0 R1133 1-216-864-91 SHORT CHIP 0 R1134 1-216-864-91 SHORT CHIP 0 R1138 1-216-864-91 SHORT CHIP 0 R1139 1-216-864-91 SHORT CHIP 0 R1140 1-216-864-91 SHORT CHIP 0 R1141 1-216-864-91 SHORT CHIP 0 R1142 1-216-864-91 SHORT CHIP 0 MV www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 8-15 Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark DVP-NS15/NS51P/NS43P/NS53P/K56P R1143 1-216-864-91 SHORT CHIP 0 R1144 1-216-295-91 SHORT CHIP 0 R1145 1-216-295-91 SHORT CHIP 0 R1146 1-216-295-91 SHORT CHIP 0 R1150 1-216-827-91 METAL CHIP 3.3K 5% 1/10W R1151 1-216-827-91 METAL CHIP 3.3K 5% 1/10W R1152 1-216-827-91 METAL CHIP 3.3K 5% 1/10W R1168 1-216-811-91 METAL CHIP 150 5% 1/10W (NS43P/NS53P/NS15) R1168 1-216-815-91 METAL CHIP 330 5% 1/10W (NS51P/K56P) R1177 1-216-864-91 SHORT CHIP 0 R1178 1-216-821-91 METAL CHIP 1K 5% 1/10W R1180 1-216-833-91 METAL CHIP 10K 5% 1/10W R1184 1-216-864-91 SHORT CHIP 0 RB105 1-234-702-21 RES, NETWORK 68 (1005X4) RB106 1-234-702-21 RES, NETWORK 68 (1005X4) RB106 1-234-702-21 RES, NETWORK 68 (1005X4) (K56P ONLY) RB107 1-234-371-21 RES, NETWORK 47 (1005X4) RB108 1-234-371-21 RES, NETWORK 47 (1005X4) RB110 1-234-400-21 CONDUCTOR, NETWORK (2010X4) RB111 1-234-400-21 CONDUCTOR, NETWORK (2010X4) RB112 1-234-400-21 CONDUCTOR, NETWORK (2010X4) RB113 1-234-400-21 CONDUCTOR, NETWORK (2010X4) X102 1-813-539-11 QUARTZ CRYSTAL UNIT (NS43P/NS53P/NS15) X102 1-813-219-31 QUARTZ CRYSTAL UNIT (NS51P/K56P) SW-467 MOUNTED PWB (NS15) SW-468 MOUNTED PWB (NS43P/NS53P) SW-469 MOUNTED PWB (K56P) SW-475 MOUNTED PWB (NS51P) ********************* C001 1-163-021-91 CERAMIC CHIP 0.01UF 10.00% 50V (NS15/NS51P) CN051 1-815-569-11 CONNECTOR, FFC/FPC 7P (K56P ONLY) CN001 1-815-569-11 CONNECTOR, FFC/FPC 7P (NS43P/NS53P) CN002 1-794-473-11 CONNECTOR, FPC/FFC 9P (NS15/NS51P) D001 6-501-147-01 DIODE LTL-1MHAE-112A (EXCEPT NS15) D002 8-719-070-74 DIODE SLR-342MCT32 (NS15 ONLY) D051 6-501-147-01 DIODE LTL-1MHAE-112A (K56P ONLY) MV IC001 6-703-744-01 IC GP1UE26SXKOF (NS15/NS51P) JR051 1-216-295-91 SHORT CHIP 0 (K56P ONLY) JR001 1-216-295-91 SHORT CHIP 0 (EXCEPT K56P) JR002 1-216-295-91 SHORT CHIP 0 (EXCEPT K56P) JR003 1-216-295-91 SHORT CHIP 0 (NS51P ONLY) JR004 1-216-295-91 SHORT CHIP 0 NS51P ONLY) R028 1-216-059-91 RES-CHIP 2.7K 5% 1/10W (EXCEPT NS15/K56P) R029 1-216-071-91 RES-CHIP 8.2K 5% 1/10W (NS43P/NS53P) R030 1-216-063-91 RES-CHIP 3.9K 5% 1/10W (NS43P/NS53P) R031 1-216-059-91 RES-CHIP 2.7K 5% 1/10W (NS43P/NS53P) R033 1-216-013-91 RES-CHIP 33 5% 1/10W (NS51P ONLY) R033 1-216-025-91 RES-CHIP 100 5% 1/10W (NS43P/NS53P) R034 1-216-017-91 RES-CHIP 47 5% 1/10W (NS15/NS51P) R036 1-216-033-91 RES-CHIP 220 5% 1/10W (NS51P ONLY) R051 1-216-059-91 RES-CHIP 2.7K 5% 1/10W (K56P ONLY) R053 1-216-025-91 RES-CHIP 100 5% 1/10W (K56P ONLY) S001 1-771-410-21 SWITCH, TACT (EXCEPT K56P) S002 1-771-410-21 SWITCH, TACT (NS43P/NS53P) S003 1-771-410-21 SWITCH, TACT (NS43P/NS53P) S004 1-771-410-21 SWITCH, TACT (EXCEPT K56P) S005 1-771-410-21 SWITCH, TACT (EXCEPT NS15/K56P) S006 1-771-410-21 SWITCH, TACT (EXCEPT K56P) S051 1-771-410-21 SWITCH, TACT (K56P ONLY) S054 1-771-410-21 SWITCH, TACT (K56P ONLY) S055 1-771-410-21 SWITCH, TACT (K56P ONLY) S056 1-771-410-21 SWITCH, TACT (K56P ONLY) SW-467 SW-478 SW-469 SW-475 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 8-16 Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark DVP-NS15/NS51P/NS43P/NS53P/K56P 1-468-971-11 POWER BLOCK (SRV1872WW) (NS51P/NS43P/NS53P:EXCEPT MX) ************************** 1-468-972-11 POWER BLOCK (SRV1873UC) ((NS53P:MX) ************************* 1-468-971-31 POWER BLOCK (SRV1872WW) (NS15) ************************* POWER BLOCK (SRV1872WW) POWER BLOCK (SRV1873UC) ACCESSORIES ************* 1-751-271-71 CORD, CONNECTION (AV) (EXCEPT NS15 / K56P:RUS) 1-569-008-21 ADAPTOR, CONVERSION 2P (NS53P:E) 2-665-741-11 MANUAL, INSTRUCTION (GERMAN) (NS15:AE1) 2-665-741-21 MANUAL, INSTRUCTION (FRENCH) (NS15:AE1) 2-665-741-31 MANUAL, INSTRUCTION (DUTCH) (NS15:AE1) 2-665-741-41 MANUAL, INSTRUCTION (ITALIAN) (NS15:AE1) 2-665-741-51 MANUAL, INSTRUCTION (SPANISH) (NS15:AE2) 2-665-741-61 MANUAL, INSTRUCTION (PORTUGUESE) (NS15:AE2) 2-665-741-71 MANUAL, INSTRUCTION (GREEK) (NS15:AE2) 2-665-742-11 MANUAL, INSTRUCTION (ENGLISH) (NS15:UK) 2-665-742-21 MANUAL, INSTRUCTION (DANISH) (NS15:AE3) 2-665-742-31 MANUAL, INSTRUCTION (FINNISH) (NS15:AE3) 2-665-742-41 MANUAL, INSTRUCTION (SWEDISH) (NS15:AE3) 2-665-742-51 MANUAL, INSTRUCTION (POLAND) (NS15:AE3) 2-665-997-11 MANUAL, INSTRUCTION (ENGLISH) (NS51P:HK,SP,MY,TW,ME,EA,IR,IN,AUS) 2-665-997-21 MANUAL, INSTRUCTION (CHINESE TRADITIONAL) (NS51P:HK) 2-665-997-31 MANUAL, INSTRUCTION (MALAY) (NS51P:MY) 2-665-997-41 MANUAL, INSTRUCTION (CHINESE TRADITIONAL) (NS51P:TW) 2-665-997-51 MANUAL, INSTRUCTION (CHINESE SIMPLIFIED) (NS51P:MY) 2-665-997-61 MANUAL, INSTRUCTION (ARABIC) (NS51P:ME2,EA) 2-665-997-71 MANUAL, INSTRUCTION (PERSIAN) PR (NS51P:IR) 2-665-997-81 MANUAL, INSTRUCTION (FRENCH) (NS51P:ME5) 2-665-997-91 MANUAL, INSTRUCTION (THAI) (NS51P:SP) 2-665-998-11 MANUAL, INSTRUCTION (CHINESE SIMPLIFIED) (NS51P:CH) 2-665-737-11 MANUAL, INSTRUCTION (KOREA) (NS51P:KR) 2-661-162-31 MANUAL, INSTRUCTION (SPANISH) (NS53P:MX,E) 2-661-213-11 MANUAL, INSTRUCTION (SPANISH) (NS53P:AR) 2-661-214-11 MANUAL, INSTRUCTION (PORTUGUESE) (NS53P:BR) 2-661-213-21 MANUAL, INSTRUCTION (SPANISH) (NS43P:AR) 2-661-214-21 MANUAL, INSTRUCTION (PORTUGUESE) (NS43P:BR) 2-662-867-11 MANUAL, INSTRUCTION (ENGLISH) (K56P:SP,EA) 2-662-867-21 MANUAL, INSTRUCTION (THAI) (K56P:SP) 2-662-867-31 MANUAL, INSTRUCTION (ARABIC) (K56P:EA) 2-665-121-11 MANUAL, INSTRUCTION (RUSSIA) (K56P:RUS) 1-479-179-21 REMOTE COMMANDER (RMT-D175P) (NS15/NS51P:EXCEPT KR,TW,CH/K56P:RUS,SP,EA) 1-479-179-11 REMOTE COMMANDER (RMT-D175A) (NS51P:KR,TW/NS43P/NS53P/K56P:TW) 1-479-671-11 REMOTE COMMANDER (RMT-D175C) (NS51P:CH) 2-662-867-41 MANUAL, INSTRUCTION (ENGLISH) (K56P:TW) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 8-17 DVP-NS15/NS51P/NS43P/NS53P/K56P – 158 – Sony Corporation Home Electronics Network Company. 9-874-899-12 2006B0800-1 2006.02 Published by Product Design 1 Department www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com
