CD/DVD PLAYER SPECIFICATIONS RMT-D143A/D143E/D143P/D144A US Model DVP-NC615/NC655P Canadian Model AEP Model UK Model E Model Australian Model Singapore Model PX Model DVP-NC615 SERVICE MANUAL System Laser: Semiconductor laser Signal format system: U.S./Canadian models: NTSC Asian/Oceanian models: PAL/NTSC UK/European models: PAL/(NTSC) (See page 1-3 to switch.) Audio characteristics Frequency response: DVD VIDEO (PCM 96 kHz): 2 Hz to 44 kHz (±1.0 dB)/DVD VIDEO (PCM 48 kHz): 2 Hz to 22 kHz (±0.5 dB)/CD: 2 Hz to 20 kHz (±0.5 dB) Signal-to-noise ratio (S/N ratio): 115 dB (LINE OUT L/R (AUDIO) jacks only) Harmonic distortion: 0.003 % Dynamic range: DVD VIDEO: 103 dB/CD: 99 dB Wow and flutter: Less than detected value (±0.001% W PEAK) The signals from LINE OUT L/R (AUDIO) jacks are measured. When you play PCM sound tracks with a 96 kHz sampling frequency, the output signals from the DIGITAL OUT (COAXIAL) jack are converted to 48 kHz sampling frequency. Outputs (Jack name: Jack type/Output level/Load impedance) LINE OUT L/R (AUDIO): Phono jack/ 2 Vrms/10 kilohms DIGITAL OUT (COAXIAL): Phono jack/ 0.5 Vp-p/75 ohms COMPONENT VIDEO OUT(Y, PB/CB, PR/ CR): Phono jack/Y: 1.0 Vp-p/PB, PR, CB, CR,: 0.7 Vp-p/75 ohms (US/Canadian/ Asian/Oceanian models) LINE OUT (VIDEO): Phono jack/1.0 Vp-p/ 75 ohms S VIDEO OUT: 4-pin mini DIN/ Y: 1.0 Vp-p/C:0.3 Vp-p (PAL), 0.286 Vp-p (NTSC)/75 ohms General Power requirements: 120 V AC, 60 Hz 110 to 240V AC, 50/60 Hz 220 to 240V AC, 50/60 Hz See page 1-1 for further information. Power consumption: 13 W/14 W See page 1-1 for further information. Mass (approx.): 5.1 kg (11 lb 4 oz) Operating temperature: 5 ° C to 35 ° C (41 °F to 95 °F) Operating humidity: 25 % to 80 % Supplied accessories See page 1-3. Specifications and design are subject to change without notice. ENERGY STARR is a U.S. registered mark. As an ENERGY STARR Partner, Sony Corporation has determined that this product meets the ENERGY STARR guidelines for energy efficiency. DIGITAL OUT (OPTICAL): Optical output jack/–18 dBm (wave length 660 nm) (UK/European models) Dimensions (approx.): 430 × 108 × 409 mm 430 × 108 × 411 mm (1 (NC615: UK, European models) 7 × 4 3/8 × 16 1/8 in.):(NC615: US, (17 × 4 3/8 × 16 3/8 in.): 430 × 108 × 413 mm (NC655P model) (17 × 4 3/8 × 16 1/4 in.): (width/height/depth) incl. projecting parts Canadian, Asian, Oceanian models) Photo : DVP-NC655P (SILVER) RMT-D144A www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com — 2 — SAFETY CHECK-OUT After correcting the original service problem, perform the following safety checks before releasing the set to the customer. 1. Check the area of your repair for unsoldered or poorly-soldered connections. Check the entire board surface for solder splashes and bridges. 2. Check the interboard wiring to ensure that no wires are "pinched" or contact high-wattage resistors. 3. Look for unauthorized replacement parts, particularly transistors, that were installed during a previous repair. Point them out to the customer and recommend their replacement. 4. Look for parts which, though functioning, show obvious signs of deterioration. Point them out to the customer and recommend their replacement. 5. Check the line cord for cracks and abrasion. Recommend the replacement of any such line cord to the customer. 6. Check the B+ voltage to see it is at the values specified. 7. Check the antenna terminals, metal trim, "metallized" knobs, screws, and all other exposed metal parts for AC leakage. Check leakage as described below. LEAKAGE TEST The AC leakage from any exposed metal part to earth ground and from all exposed metal parts to any exposed metal part having a return to chassis, must not exceed 0.5mA (500 microampers). Leakage current can be measured by any one of three methods. 1. A commercial leakage tester, such as the Simpson 229 or RCA TW-540A. Follow the manufacturers' instructions to use these instruments. 2. A battery-operated AC milliammeter. The Data Precision 245 digital multimeter is suitable for this job. 3. Measuring the voltage drop across a resistor by means of a VOM or battery-operated AC voltmeter. The "limit" indication is 0.75V, so analog meters must have an accurate low voltage scale. The Simpson 250 and Sanwa SH-63Trd are examples of a passive VOM that is suitable. Nearly all battery operated digital multimeters that have a 2V AC range are suitable. (See Fig. A) Unleaded solder Boards requiring use of unleaded solder are printed with the lead- free mark (LF) indicating the solder contains no lead. (Caution: Some printed circuit boards may not come printed with the lead free mark due to their particular size.) : LEAD FREE MARK Unleaded solder has the following characteristics. • Unleaded solder melts at a temperature about 40°C higher than ordinary solder. Ordinary soldering irons can be used but the iron tip has to be applied to the solder joint for a slightly longer time. Soldering irons using a temperature regulator should be set to about 350°C. Caution: The printed pattern (copper foil) may peel away if the heated tip is applied for too long, so be careful! • Strong viscosity Unleaded solder is more viscous (sticky, less prone to flow) than ordinary solder so use caution not to let solder bridges occur such as on IC pins, etc. • Usable with ordinary solder It is best to use only unleaded solder but unleaded solder may also be added to ordinary solder. SAFETY-RELATED COMPONENT WARNING!! COMPONENTS IDENTIFIED BY MARK 0 OR DOTTED LINE WITH MARK 0 ON THE SCHEMATIC DIAGRAMS AND IN THE PARTS LIST ARE CRITICAL TO SAFE OPERATION. REPLACE THESE COMPONENTS WITH SONY PARTS WHOSE PART NUMBERS APPEAR AS SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUBLISHED BY SONY. ATTENTION AU COMPOSANT AYANT RAPPORT À LA SÉCURITÉ! LES COMPOSANTS IDENTIFÉS PAR UNE MARQUE 0 SUR LES DIAGRAMMES SCHÉMATIQUES ET LA LISTE DES PIÈCES SONT CRITIQUES POUR LA SÉCURITÉ DE FONCTIONNEMENT. NE REMPLACER CES COMPOSANTS QUE PAR DES PIÈSES SONY DONT LES NUMÉROS SONT DONNÉS DANS CE MANUEL OU DANS LES SUPPÉMENTS PUBLIÉS PAR SONY. To Exposed Metal Parts on Set 0.15 µF 1.5 kΩ AC Voltmeter (0.75 V) Earth Ground Fig. A. Using an AC voltmeter to check AC leakage. CAUTION Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure. WARNING!! WHEN SERVICING, DO NOT APPROACH THE LASER EXIT WITH THE EYE TOO CLOSELY. IN CASE IT IS NECESSARY TO CONFIRM LASER BEAM EMISSION, BE SURE TO OBSERVE FROM A DISTANCE OF MORE THAN 25 cm FROM THE SURFACE OF THE OBJECTIVE LENS ON THE OPTICAL PICK-UP BLOCK. CAUTION: The use of optical instrument with this product will increase eye hazard. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com — 3 — TABLE OF CONTENTS SERVICE NOTE 1. NOTE ON REMOVING THE UPPER CASE ··················· 5 2. DISC REMOVAL PROCEDURE ······································ 5 3. NOTE ON REMOVING THE TABLE ASS’Y ·················· 5 4. NOTE ON MOUNTING THE GEARS ····························· 6 5. HOW TO SERVICE THE MB-103 BOARD ····················· 7 6. CONNECTION OF SERVICE JIG ···································· 9 1. GENERAL Precautions·············································································1-1 About this Manual ·································································1-1 This Player Can Play the Following Discs ····························1-1 Notes about the Discs ····························································1-1 Index to Parts and Controls····················································1-2 Guide to On-Screen Displays (Control Bar)··························1-3 Simple Start Guide ····································································1-3 Quick Overview ·····································································1-3 Step 1: Unpacking ·································································1-3 Step 2: Inserting Batteries into the Remote ···························1-3 Step 3: TV Hookups ······························································1-3 Step 4: Playing a Disc ····························································1-4 Hookups·····················································································1-4 Hooking Up the Player ··························································1-4 Step 1: Connecting the Video Cords ······································1-4 Step 2: Connecting the Audio Cords ·····································1-4 Step 3: Connecting the Power Cord·······································1-6 Step 4: Quick Setup ·······························································1-6 Playing Discs ·············································································1-6 Playing Discs ·········································································1-6 Searching for a Particular Point on a Disc (Scan, Slow-motion Play, Search, Freeze Frame) ···············································1-7 Resuming Playback from the Point Where You Stopped the Disc (Resume Play/Multi-disc Resume)·····························1-7 Using the DVD’s Menu ·························································1-8 Playing VIDEO CDs with PBC Functions (PBC Playback) · 1-8 Playing an MP3 Audio Track·················································1-8 Various Play Mode Functions (Program Play, Shuffle Play, Repeat Play, A-B Repeat Play) ···········································1-9 Searching for a Scene ······························································1-10 Searching for a Title/Chapter/Track/Index/Scene (Search mode) ···································································1-10 Viewing Information About the Disc·······································1-10 Checking the Playing Time and Remaining Time ···············1-10 Sound Adjustments ··································································1-11 Changing the Sound·····························································1-11 TV Virtual Surround Settings (TVS) ···································1-11 Enjoying Movies ·····································································1-12 Changing the Angles ····························································1-12 Displaying the Subtitles ·······················································1-12 Adjusting the Picture Quality (BNR) ··································1-12 Adjusting the Playback Picture (CUSTOM PICTURE MODE)·· 1-12 Enhancing the Playback Picture (DIGITAL VIDEO ENHANCER) ···································································1-13 Using Various Additional Functions ········································1-13 Locking Discs (CUSTOM PARENTAL CONTROL, PARENTAL CONTROL) ·················································1-13 Controlling Your TV with the Supplied Remote ·················1-14 Settings and Adjustments ························································1-15 Using the Setup Display ······················································1-15 Setting the Display or Sound Track Language (LANGUAGE SETUP) ····················································1-15 Settings for the Display (SCREEN SETUP) ·······················1-15 Custom Settings (CUSTOM SETUP) ·································1-15 Settings for the Sound (AUDIO SETUP) ····························1-16 Additional Information ····························································1-16 Troubleshooting ···································································1-16 Self-diagnosis Function (When letters/numbers appear in the display) ·······································································1-17 Glossary ···············································································1-17 Language Code List ·····························································1-18 2. DISASSEMBLY 2-1. DISASSEMBLY······························································2-1 2-2. UPPER CASE ·································································2-1 2-3. FRONT PANEL SECTION·············································2-2 2-4. REAR PANEL ·································································2-2 2-5. MB-103 BOARD·····························································2-3 2-6. CN-158 BOARD ·····························································2-3 2-7. AV-062 BOARD ······························································2-4 2-8. ER-14 BOARD (AEP, UK) ·············································2-4 2-9. TABLE ASS’Y ································································2-4 2-10. LOADING MOTOR ASS’Y ···········································2-5 2-11. OPTICAL PICK-UP························································2-5 2-12. POWER BLOCK·····························································2-6 2-13. IF-091 AND FR-187 BOARDS ······································2-6 2-14. INTERNAL VIEWS························································2-7 2-15. CIRCUIT BOARDS LOCATION ···································2-8 3. BLOCK DIAGRAMS 3-1. OVERALL BLOCK DIAGRAM ····································3-1 3-2. RF/SERVO BLOCK DIAGRAM ····································3-3 3-3. SIGNAL PROCESSOR BLOCK DIAGRAM ················3-5 3-4. SYSTEM CONTROL BLOCK DIAGRAM ···················3-7 3-5. VIDEO BLOCK DIAGRAM (NC655P)·························3-9 3-6. VIDEO BLOCK DIAGRAM (NC615) ·························3-11 3-7. AUDIO BLOCK DIAGRAM ········································3-13 3-8. INTERFACE CONTROL BLOCK DIAGRAM ···········3-15 3-9. POWER BLOCK DIAGRAM (1/2) ······························3-17 3-10. POWER BLOCK DIAGRAM (2/2) ······························3-19 4. PRINTED WIRING BOARDS AND SCHEMATIC DIAGRAMS 4-1. FRAME SCHEMATIC DIAGRAM································4-1 4-2. PRINTED WIRING BOARDS AND SCHEMATIC DIAGRAM ······································································4-4 WAVEFORMS ································································4-5 • MB-103(DVD/CD RF AMP, DIGITAL SERVO, MOTOR DRIVE, SERVO, AV DECODER, SDRAM, SYSTEM CONTROL, AUDIO DAC, PLL, I/P CONVERTER, VIDEO ENCODER) PRINTED WIRING BOARD ·························4-7 • MB-103 (DVD/CD RF AMP, DIGITAL SERVO) (1/8) SCHEMATIC DIAGRAM ····························4-11 • MB-103 (MOTOR DRIVE) (2/8) SCHEMATIC DIAGRAM ····························4-13 • MB-103 (SERVO) (3/8) SCHEMATIC DIAGRAM ····························4-15 • MB-103 (AV DECODER) (4/8) SCHEMATIC DIAGRAM ····························4-17 • MB-103 (SDRAM) (5/8) SCHEMATIC DIAGRAM ····························4-19 • MB-103 (SYSTEM CONTROL) (6/8) SCHEMATIC DIAGRAM ····························4-21 • MB-103 (AUDIO DAC, PLL) (7/8) SCHEMATIC DIAGRAM ····························4-23 • MB-103 (I/P CONVERTER, VIDEO ENCODER) (8/8) SCHEMATIC DIAGRAM ····························4-25 • AV-062 (AUDIO OUT, VIDEO OUT) PRINTED WIRING BOARD ·······················4-29 • AV-062 (AUDIO OUT) (1/2) SCHEMATIC DIAGRAM ····························4-31 • AV-062 (VIDEO OUT) (2/2) SCHEMATIC DIAGRAM ····························4-33 • ER-14 (LINE1 OUT) (NC615:AEP,UK) PRINTED WIRING BOARD ·······················4-35 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com — 4 — • ER-14 (LINE1 OUT) (NC615:AEP,UK) SCHEMATIC DIAGRAM ····························4-37 • IF-091 (IF COM), PL-031 (LED) PRINTED WIRING BOARDS ·····················4-39 • IF-091 (IF COM) SCHEMATIC DIAGRAM ····························4-41 • FR-187 (FUNCTION SW/LED) PRINTED WIRING BOARD ·······················4-43 • FR-187 (FUNCTION SW/LED) SCHEMATIC DIAGRAM ····························4-45 • CN-158 (CONNECTOR) PRINTED WIRING BOARD ·······················4-47 • CN-158 (CONNECTOR) SCHEMATIC DIAGRAM ····························4-49 • SE-130 (SENSOR), MD-94 (MD INTERFACE) PRINTED WIRING BOARD ·······················4-51 • SE-130 (SENSOR), MD-94 (MD INTERFACE) SCHEMATIC DIAGRAM ····························4-53 • HS10S1U, HS10S1F (SWITCHING REGULATOR) PRINTED WIRING BOARDS ·····················4-55 • HS10S1U, HS10S1F (SWITCHING REGULATOR) SCHEMATIC DIAGRAM ····························4-57 5. IC PIN FUNCTION DESCRIPTION 5-1. SYSTEM CONTROL PIN FUNCTION (MB-103 BOARD IC104: MB91307RPFV-G-BND-E1) ·5-1 6. TEST MODE 6-1. GENERAL DESCRIPTION ···········································6-1 6-2. STARTING TEST MODE···············································6-1 6-3. SYSCON DIAGNOSIS ···················································6-1 6-4. DRIVE AUTO ADJUSTMENT ······································6-5 6-5. DRIVE MANUAL OPERATION ···································6-7 6-6. MECHA AGING ···························································6-11 6-7. EMERGENCY HISTORY ············································6-11 6-8. VERSION INFORMATION ·········································6-11 6-9. VIDEO LEVEL ADJUSTMENT ··································6-11 6-10. IF CON SELF DIAGNOSTIC FUNCTION ·················6-12 6-11. TROUBLESHOOTING ················································6-19 6-12. MECHANISM TEST MODE ADJUSTMENT ···········6-22 6-12-1. How to enter the mechanism test mode ······················6-22 6-12-2. Types of the mechanism test mode ·····························6-22 6-12-3. Description of Each Mode ··········································6-22 7. ELECTRICAL ADJUSTMENT 7-1. POWER SUPPLY ADJUSTMENT ·································7-1 1. Power Supply Check (HS10S1U/HS10S1F Boards) ······7-1 7-2. ADJUSTMENT OF VIDEO SYSTEM···························7-2 1. Video Level Adjustment (MB-103 Board) ······················7-2 2. Progressive Video Output Level Adjustment (MB-103 Board) ······························································7-2 3. Checking S Video Output S-Y·········································7-2 4. Checking S Video Output S-C ·········································7-2 5. Checking Component Video Output Y (US, Canadian, Australian, PX Model) ···························7-3 6. Checking Component Video Output B-Y (US, Canadian, Australian, PX Model) ···························7-3 7. Checking Component Video Output R-Y (US, Canadian, Australian, PX Model) ···························7-3 8. Checking RGB Output R (AEP, UK Model)···················7-3 9. Checking RGB Output G (AEP, UK Model) ··················7-4 10. Checking RGB Output B (AEP, UK Model)···················7-4 7-3. ADJUSTMENT RELATED PARTS ARRANGEMENT ··· 7-5 8. REPAIR PARTS LIST 8-1. EXPLODED VIEWS ······················································8-1 8-1-1.OVERALL SECTION·····················································8-2 8-1-2.FRONT PANEL SECTION·············································8-3 8-1-3.LOADING SECTION ·····················································8-4 8-1-4.CHASSIS SECTION·······················································8-5 8-2. ELECTRICAL PARTS LIST ··········································8-6 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com — 5 — 1. NOTE ON REMOVING THE UPPER CASE 1) Remove the four tapping screws and three screws. (See Fig. 1) 2) Open the sides of case. (See Fig. 1) 3) Remove the upper case in the direction of the arrow A. 2. DISC REMOVAL PROCEDURE 1) Insert a flat-head (-) screwdriver into a hole at the bottom, and rotate the cam gear in the direction of the arrow A. (See Fig.2) Two tapping screws Two tapping screws Three screws (B3) A 3. NOTE ON REMOVING THE TABLE ASS’Y 1) Remove the two screws. (See Fig. 3) A Cam gear Table Hole Screw (M2.6 × 8) Screw (M2.6 × 8) 2) Remove the two Plates (guide) in the direction of the arrows A and B. 3) Remove the Table ass’y in the direction of the arrow C. 4) Remove the Flexible flat cable (See Fig. 4). A B C Plate (guide) Plate (guide) Table ass'y Flexible flat cable (FMS-18: CN002) Fig. 1. Fig. 2. Fig. 3. Fig. 4. SERVICE NOTE www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com — 6 — 4. NOTE ON MOUNTING THE GEARS 1) Mount the gear (chuck). (See Fig. 5) 2) Rotate the gear (chuck) in the direction of the arrow. (down position) (See Fig. 5) 3) Connect the boss of the gear (swing) with the groove of the rotary encoder and mount the gear (swing). (See Fig. 6) 4) Align triangle mark of the chassis with the groove of the gear (swing). Gear (chuck) Gear (swing) Gear (swing) Boss Groove Align triangle mark of the chassis with the groove of the gear (swing). 5) Mount the gear (idler) while aligning the engagement of the gear (swing) and the gear (chuck). (See Fig. 7) Gear (idler) Gear (idler) Gear (chuck) Gear (swing) Engagement the gear (swing) and the gear (chuck). Fig. 5. Fig. 6. Fig. 7. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com — 7 — 5. HOW TO SERVICE THE MB-103 BOARD 1) Remove the upper case from the set. (Refer to section 2-1) 2) Remove the MB-103 board. (Refer to section 2-4) 3) Set the MB-103 board in the stand (with CK-121 board) as shown in Fig. 9. FFC 26P J-6090-117-A, FFC 9P J-6090-118-A, FFC 15P J-6090-121-A, FFC 25P J-6090-122-A, FFC 11P J-6090-120-A Harness 6P (J-6090-126-A) CK-120 board (J-6090-127-A) Stand (CK-121 board) (J-6090-132-A) Five flexible flat cables Jig 4) Set the CK-120 board in the place where the MB-103 board is removed, as shown in Fig. 10. 3 Connector (CN101) 2 Stand (with CK-121 board) 1 MB-103 board 4 Two screws (B3) 5 Connector (CN109) 6 Board to board connector (CN111) 1 CK-120 board 2 Four screws (B3) 4 Flexible flat cable (FMO-6: CN103) 3 Flexible flat cable (FMM-42: CN101) 7 Flexible flat cable (FMC-15: CN107) Fig. 8. Fig. 9. Fig. 10. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com — 8 — 5) Set the four flexible flat cables as shown in Fig. 11. 6) Set the flexible flat cable and the harness as shown in Fig. 12. 4 Connector (CN110) 4 Connector (CN201) 5 Harness (6P: CN102) 3 Flexible flat cable (FFC 25P: CN601) 4 Connector (CN102) 5 Connector (CN104) 6 Connector (CN108) 8 Connector (CN112) 3 Flexible flat cable (FFC 11P: CN201) 7 Flexible flat cable (FFC 15P: CN201) 2 Flexible flat cable (FFC 9P: CN204) 1 Flexible flat cable (FFC 26P: CN203) 7) Set is finished. Fig. 11. Fig. 12. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com — 9 — CK-120 board Mechanism deck CN-158 MB-103 board AV-62 board Stand (CK-121 board) B to B Connector 9P B to B Connector 9P FFC 26P (Used the set) FFC 9P (Used the set) FFC 11P (Used the set) HARNESS 6P HARNESS 6P (Used the set) FFC 26P FFC 9P FFC 11P FFC15P FFC25P CN101 CN102 CN103 CN104 CN107 CN108 CN110 CN203 CN204 CN201 CN102 CN111 CN109 CN308 CN311 CN301 CN112 CN201 CN202 CN101 CN601 CN201 6. CONNECTION OF SERVICE JIG www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com — 10 — MEMO www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 1-1 SECTION 1 GENERAL DVP-NC615/NC655P This section is extracted from instruction manual. (DVP-NC615 : 3-074-252-11) 3 Precautions • The power requirements and power consumption of this player are indicated on the back of the player. Check that the player’s operating voltage is identical with your local power supply. Power requirements and power consumption t On safety • Caution – The use of optical instruments with this product will increase eye hazard. • To prevent fire or shock hazard, do not place objects filled with liquids, such as vases, on the apparatus. • Should any solid object or liquid fall into the cabinet, unplug the player and have it checked by qualified personnel before operating it any further. On power sources • The player is not disconnected from the AC power source as long as it is connected to the wall outlet, even if the player itself has been turned off. • If you are not going to use the player for a long time, be sure to disconnect the player from the wall outlet. To disconnect the AC power cord, grasp the plug itself; never pull the cord. • Should the AC power cord need to be changed, have it done at a qualified service shop only. On placement • Place the player in a location with adequate ventilation to prevent heat build-up in the player. • Do not place the player on a soft surface such as a rug that might block the ventilation holes. • Do not place the player in a location near heat sources, or in a place subject to direct sunlight, excessive dust, or mechanical shock. • Do not install the player in an inclined position. It is designed to be operated in a horizontal position only. • Keep the player and discs away from equipment with strong magnets, such as microwave ovens, or large loudspeakers. • Do not place heavy objects on the player. For the model supplied with the AC plug adaptor If the AC plug of your unit does not fit into the wall outlet, attach the supplied AC plug adaptor. On operation • If the player is brought directly from a cold to a warm location, or is placed in a very damp room, moisture may condense on the lenses inside the player. Should this occur, the player may not operate properly. In this case, remove the disc and leave the player turned on for about half an hour until the moisture evaporates. • When you move the player, take out any discs. If you don’t, the disc may be damaged. On adjusting volume Do not turn up the volume while listening to a section with very low level inputs or no audio signals. If you do, the speakers may be damaged when a peak level section is played. On cleaning Clean the cabinet, panel, and controls with a soft cloth slightly moistened with a mild detergent solution. Do not use any type of abrasive pad, scouring powder or solvent such as alcohol or benzine. On cleaning discs Do not use a commercially available cleaning disc. It may cause a malfunction. IMPORTANT NOTICE Caution: This player is capable of holding a still video image or on-screen display image on your television screen indefinitely. If you leave the still video image or on-screen display image displayed on your TV for an extended period of time you risk permanent damage to your television screen. Projection televisions are especially susceptible to this. DVP–XXXX 00V 00Hz 00W NO. 0-000-000-00 X 4 On transporting the player Before transporting the player, follow the procedure below to return the internal mechanisms to their original positions. 1 Remove all the discs from the disc tray. 2 Press Z to close the disc tray. Make sure that “NO DISC” appears on the front panel display. 3 Press ?/1 to turn off the player. The player enters standby mode and the power indicator lights up in red. 4 Disconnect the AC power cord. If you have any questions or problems concerning your player, please consult your nearest Sony dealer. 7 About this Manual • Instructions in this manual describe the controls on the remote. You can also use the controls on the player if they have the same or similar names as those on the remote. • The meaning of the icons used in this manual is described below: * MP3 (MPEG1 Audio Layer 3) is a standard format defined by ISO (International Standard Organization)/MPEG which compresses audio data. This Player Can Play the Following Discs The “DVD VIDEO” logo is a trademark. Region code Your player has a region code printed on the back of the unit and only will play DVD VIDEO discs (playback only) labeled with identical region codes. This system is used to protect copyrights. DVDs labeled will also play on this player. If you try to play any other DVD, the message “Playback prohibited by area limitations..” will appear on the TV screen. Depending on the DVD, no region code indication may be labeled even though playing the DVD is prohibited by area restrictions. Example of discs that the player cannot play The player cannot play the following discs: • All CD-ROMs (including PHOTO CDs)/ CD-Rs/CD-RWs other than those recorded in the following formats: –music CD format –video CD format –MP3 format that conforms to ISO9660* Level 1/Level 2, or its extended format, Joliet • Data part of CD-Extras • DVD-RWs in VR mode Check your model The instructions in this manual are for DVP-NC615 sold in the U.S.A., Canada, Asia and Oceania. The differences between U.S./Canadian models and Asian/Oceanian models are the supplied remote commander, RMT-D143A for U.S./ Canadian models or RMT-D143E for Asian/Oceanian models, jack names on the rear panel, and some of the on-screen displays. U.S./Canadian model is the one used for illustration purposes unless otherwise specified. Any difference in operation is clearly indicated in the text, for example, “Asian/Oceanian models only.” Icon Meaning Functions available for DVD VIDEOs or DVD-Rs/DVD- RWs in video mode Functions available for VIDEO CDs or CD-Rs/CD-RWs in video CD format Functions available for DATA CDs (CD-ROMs/CD-Rs/CD- RWs containing MP3* audio tracks) Functions available for music CDs or CD-Rs/CD-RWs in music CD format Format of discs DVD VIDEO VIDEO CD Music CD ALL DVP–XXXX 00V 00Hz 00W NO. 0-000-000-00 X Region code 8 • DVD-ROMs • DVD Audio discs • HD layer on Super Audio CDs * A logical format of files and folders on CD- ROMs defined by ISO (International Standard Organization). Also, the player cannot play the following discs: • A DVD with a different region code. • A disc that has a non-standard shape (e.g., card, heart). • A disc with paper or stickers on it. • A disc that has the adhesive of cellophane tape or a sticker still left on it. For U.S./Canadian models only: • The player cannot play a disc recorded in a color system other than NTSC, such as PAL or SECAM (this player conforms to the NTSC color system). Note Some CD-Rs, CD-RWs, DVD-Rs, or DVD-RWs (in video mode) cannot be played on this player due to the recording quality or physical condition of the disc, or the characteristics of the recording device. Furthermore, the disc will not play if it has not been correctly finalized. For more information, see the operating instructions for the recording device. Note that discs created in the Packet Write format cannot be played. Note on playback operations of DVDs and VIDEO CDs Some playback operations of DVDs and VIDEO CDs may be intentionally set by software producers. Since this player plays DVDs and VIDEO CDs according to the disc contents the software producers designed, some playback features may not be available. Also, refer to the instructions supplied with the DVDs or VIDEO CDs. Copyrights This product incorporates copyright protection technology that is protected by method claims of certain U.S. patents, other intellectual property rights owned by Macrovision Corporation, and other rights owners. Use of this copyright protection technology must be authorized by Macrovision Corporation, and is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision Corporation. Reverse engineering or disassembly is prohibited. Notes about the Discs • To keep the disc clean, handle the disc by its edge. Do not touch the surface. • Do not expose the disc to direct sunlight or heat sources such as hot air ducts, or leave it in a car parked in direct sunlight as the temperature may rise considerably inside the car. • After playing, store the disc in its case. • Clean the disc with a cleaning cloth. Wipe the disc from the center out. • Do not use solvents such as benzine, thinner, commercially available cleaners, or anti-static spray intended for vinyl LPs. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 1-2 9 Index to Parts and Controls For more information, refer to the pages indicated in parentheses. Front panel A [/1 (on/standby) button/indicator (28) Lights up in green when the power is on and lights up in red when the player is in standby mode. B DISC SELECT 1 – 5 buttons (29) C (remote sensor) (15) D Front panel display (10) E H (playback) button (28) The H button has a tactile dot.* F X (pause) button (29) G x (stop) button (29) H ./> (previous/next) buttons (29) I A (open/close) button (28) J DISC SKIP button (28) K EXCHANGE button (30) L Disc tray (28) M SURROUND button (47) N LOAD button (29) O PICTURE MODE button (52) * Use the tactile dot as a reference when operating the player. c continued 10 Front panel display When playing back a DVD When playing back a VIDEO CD with Playback Control (PBC) (33) When playing back a CD, DATA CD (MP3 audio), or VIDEO CD (without PBC) Playing time (45) Disc type Current audio signal (47) Lights up when you can change the angle (50) Current play mode (37) Playing status Current title and chapter (45) Current disc All discs mode (37) Disc numbers (29) For Asian/Oceanian models only Lights up when the player outputs the signal in NTSC format Disc type Playing time (45) Playing status Lights up during A-B Repeat Play (41) All discs mode (37) Current disc Current scene (45) For Asian/Oceanian models only Lights up when the player outputs the signal in NTSC format Disc numbers (29) Playing time (45) Disc type Current track and index (45) Lights up when playing MP3 audio tracks (34) Playing status Current disc Current play mode (37) All discs mode (37) Disc numbers (29) For Asian/Oceanian models only Lights up when the player outputs the signal in NTSC format 11 Rear panel A DIGITAL OUT (COAXIAL) jack (22) (23) (24) B LINE OUT L/R (AUDIO) jacks (21) (22) (23) C LINE OUT (VIDEO) jack (18) D S VIDEO OUT jack (18) E COMPONENT VIDEO OUT jacks (18) (The jack names differ depending on the models. U.S./Canadian models: Y, PB, PR Asian/Oceanian models: Y, CB, CR) c continued 12 Remote A TV [/1 (on/standby) button (59) B Z OPEN/CLOSE button (28) C Number buttons (33) The number 5 button has a tactile dot.* D CLEAR button (37) E SUBTITLE button (50) F AUDIO button (46) G ./> PREV/NEXT (previous/ next) buttons (29) H m/M SCAN/SLOW buttons (31) I X PAUSE button (29) J H PLAY button (28) The H button has a tactile dot.* K C/X/x/c buttons (33) L DISPLAY button (13) M TOP MENU button (33) N [/1 (on/standby) button (28) O VOL (volume) +/– buttons (59) The + button has a tactile dot.* P TV/VIDEO button (59) Q TIME/TEXT button (44) R DISC SKIP button (28) S ANGLE button (50) T PICTURE MODE button (52) U SUR (surround) button (47) V REPEAT button (40) W REPLAY button (29) X SEARCH MODE button (43) Y x STOP button (29) Z ENTER button (25) wj O RETURN button (33) wk MENU button (33) (34) * Use the tactile dot as a reference when operating the player. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 1-3 13 Guide to On-Screen Displays (Control Bar) The following explains the Control Bar. The Control Bar is used for making adjustments to the settings or displaying information during playback. The displayed contents differ according to the type of disc being played. The numbers in parentheses indicate reference pages. Displaying the Control Bar during playback The following displays appear when the DISPLAY button is pressed repeatedly during playback. You can select the setting that suits the current playback item and view the related information. NDisplay 1 The following play modes 1~5 can be set. The indicator lights up in blue when activated. Example: When Repeat Play is selected. (The display will differ when A-B Repeat Play is set.) A Disc mode (37) B Repeat Play (40) C Shuffle Play (39) D Program Play (37) E A-B Repeat Play (41) F Unit being repeated in this example. m NDisplay 2 The following play modes 7~0 can be set. The indicator lights up in blue when activated. Example: When “TVS” is set. G TVS (47) H “BNR” (51) I “CUSTOM PICTURE MODE” (52) J “DIGITAL VIDEO ENHANCER” (53) K Playback status (NPlayback, XPause, xStop, etc.) m NDisplay 3 The following playback information is displayed. Example: When playing a DVD. L TIME/TEXT icon M Disc number and type N Title number of the DVD (44) O Chapter number of the DVD (44) P Playing time or remaining time (44) m NDisplay 4 (DVD playback only) Q Format of the current audio signal (47) m NNo display m NReturn to Display 1 CHAPTER 1 2 3 4 5 6 7 8 9 q; qa T41 – 8 3:DVD T 1:01:57 qh qg qf qd qs DOLBY DIGITAL 3/2.1 qj c continued 14 Displaying the Control Bar in stop mode The following displays appear when the DISPLAY button is repeatedly pressed during stop mode. You can make basic adjustments and customize the player to suit your viewing preferences. NDisplay 1 The following settings can be made. A SETUP (61) • Select QUICK to make the minimum number of basic adjustments for using the player. • Select CUSTOM to make a full range of adjustments. • Select RESET to return the SETUP adjustments to the default settings. B PARENTAL CONTROL(55) • Set this to limit the playback of selected discs on this player. m NDisplay 2 Shows the same information as Display 1 during playback. m NDisplay 3 Shows the same information as Display 2 during playback. m NDisplay 4 Shows the same information as Display 3 during playback. m NNo display m NReturn to Display 1 QUICK CHAPTER T41 – 8 3:DVD T 1:01:57 15 Simple Start Guide Simple Start Guide Quick Overview A quick overview presented in this guide will give you enough information to start using the player for your enjoyment. To use the surround sound features of this player, refer to “Hookups” on page 18. Notes • You cannot connect this player to a TV that does not have a video input jack. • Be sure to disconnect the power of each component before connecting. Step 1: Unpacking Check that you have the following items: • Audio/video cord (pinplug × 3 y pinplug × 3) (1) • Remote commander (remote) (1) • Size AA (R6) batteries (2) • A plug adapter is included with some models. Step 2: Inserting Batteries into the Remote You can control the player using the supplied remote. Insert two Size AA (R6) batteries by matching the 3 and # ends on the batteries to the markings inside the compartment. When using the remote, point it at the remote sensor on the player. Notes • Do not leave the remote in an extremely hot or humid place. • Do not drop any foreign object into the remote casing, particularly when replacing the batteries. • Do not expose the remote sensor to direct light from the sun or a lighting apparatus. Doing so may cause a malfunction. • If you do not use the remote for an extended period of time, remove the batteries to avoid possible damage from battery leakage and corrosion. 16 Step 3: TV Hookups Connect the supplied audio/video cord and the power cord in the order (1~3) shown below. Be sure to connect the power cord last. Depending on the TV type, the image of some discs may not fit your TV screen. If you want to change the aspect ratio, please refer to page 63. When connecting to a monaural TV Use a stereo-mono conversion cord (not supplied). Connect the LINE OUT (VIDEO) jack on the player to the TV’s video input jack, and connect the LINE OUT L/R (AUDIO) jacks to the TV’s audio input jack. For Asian/Oceanian models only To change the color system The color system of the player is set to NTSC or PAL. If the on-screen menu of the player does not appear on the TV, change the color system of the player to the same color system (PAL or NTSC) of your TV. To change the color system, hold ?/1 down for a few seconds while pressing X on the player. z Hint To check the current setting of the player’s color system, press ?/1. The ?/1 indicator lights up in green. When “NTSC” appears on the front panel display, the color system of the player is set to NTSC. When “NTSC” does not appear, the color system is set to PAL. 1 Audio/video cord (supplied) 2 Power source CD/DVD Player to video input to audio input TV to LINE OUT (VIDEO) to LINE OUT L/R (AUDIO) 3 Power source LINE OUT l : Signal flow www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 1-4 17 Simple Start Guide Step 4: Playing a Disc A Turn on the TV. B Press [/1 on the player. C Switch the input selector on your TV so that the signal from the player appears on the TV screen. D Press A on the player to open the disc tray. E Place the disc on the tray with the playback side facing down. F Press H. The disc tray closes and the player begins playing the disc. After Step 6 Depending on the disc, a menu may be displayed on the TV screen. If so, select the item you want from the menu and play the DVD (page 33) or VIDEO CD disc (page 33). To stop playing Press x. To remove the disc Press A. To turn off the player Press [/1. The player enters standby mode and the power indicator lights up in red. With the playback side facing down Disc compartment number 18 Hookups Hooking Up the Player Follow Steps 1 to 4 to hook up and adjust the settings of the player. Before you start, disconnect the power cords, check that you have all of the supplied accessories, and insert the batteries into the remote (page 15). Notes • Plug cords securely to prevent unwanted noise. • Refer to the instructions supplied with the components to be connected. Step 1: Connecting the Video Cords Connect this player to your TV monitor, projector, or AV amplifier (receiver) using a video cord. Select one of the patterns A through C, according to the input jack on your TV monitor, projector, or AV amplifier (receiver). l : Signal flow Component video cord (not supplied) (yellow) Audio/video cord (supplied) TV, projector or AV amplifier (receiver) CD/DVD player TV, projector or AV amplifier (receiver) (green) S VIDEO cord (not supplied) TV, projector or AV amplifier (receiver) (red) (blue) (yellow) (green) (blue) (red) to LINE OUT (VIDEO) 19 Hookups A If you are connecting to a video input jack Connect the yellow plug of the audio/video cord (supplied) to the yellow (video) jacks. You will enjoy standard quality images. Use the red and white plugs to connect to the audio input jacks (page 21). (Do this if you are connecting to a TV only.) B If you are connecting to an S VIDEO input jack Connect an S VIDEO cord (not supplied). You will enjoy high quality images. C If you are connecting to a monitor, projector, or AV amplifier (receiver) having component video input jacks (Y/PB/PR or Y/CB/CR) Connect the component via the COMPONENT VIDEO OUT jacks using a component video cord (not supplied) or three video cords (not supplied) of the same kind and length. You will enjoy accurate color reproduction and high quality images. Notes • Connect the player directly to the TV. If you pass the player signals via the VCR, you may not receive a clear image on the TV screen. • For Asian/Oceanian models only You can switch the player’s color system to match the color system of the connected TV (page 16). Yellow (Video) White (L) Red (R) Yellow (Video) White (L) Red (R) Green Blue Red Green Blue Red VCR CD/DVD player TV Connect directly c continued 20 Step 2: Connecting the Audio Cords Refer to the chart below to select the connection that best suits your system. Be sure to also read the instructions for the components you wish to connect. Select a connection Select one of the following connections, through . * Manufactured under license from Dolby Laboratories. “Dolby,” “Pro Logic,” and the double-D symbol are trademarks of Dolby Laboratories. ** “DTS” and “DTS Digital Out” are trademarks of Digital Theater Systems, Inc. Components to be connected Connection Your setup TV • Surround effects: TVS DYNAMIC (page 48), TVS WIDE (page 48) (page 21) Example Stereo amplifier (receiver) and two speakers • Surround effects: TVS STANDARD (page 48) or MD deck/DAT deck • Surround effects: none (page 22) Example AV amplifier (receiver) having a Dolby* Surround (Pro Logic) decoder and 3 to 6 speakers • Surround effects: Dolby Surround (Pro Logic) (page 66) (page 23) Example AV amplifier (receiver) with a digital input jack having a Dolby Digital, MPEG audio or DTS** decoder and 6 speakers • Surround effects: Dolby Digital (5.1ch) (page 66), DTS (5.1ch) (page 67), MPEG audio (5.1ch) (page 67) (page 24) Example A D A B C D www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 1-5 21 Hookups Connecting to your TV This connection will use your TV speakers for sound. * The yellow plug is used for video signals (page 18). z Hint When connecting to a monaural TV, use a stereo- mono conversion cord (not supplied). Connect the LINE OUT L/R (AUDIO) jacks to the TV’s audio input jack. A TV l : Signal flow CD/DVD player (white) (red) Audio/video cord (supplied) to audio input (yellow) (white) (red) (yellow)* to LINE OUT L/R (AUDIO) c continued 22 Connecting to a stereo amplifier (receiver) and 2 speakers/Connecting to an MD deck or DAT deck If the stereo amplifier (receiver) has audio input jacks L and R only, use . If the amplifier (receiver) has a digital input jack, or when connecting to an MD deck or DAT deck, use . In this case, you can also connect the player directly to the MD deck or DAT deck without using your stereo amplifier (receiver). z Hint In connection , you can use the supplied audio/video cord instead of using a separate audio cord. Note If you select one of the TVS effects (page 47) while playing a disc, no sound will come from your speakers with the connection. B B-1 B-2 CD/DVD player or Stereo amplifier (receiver) MD deck/DAT deck Front (L) Front (R) [Speakers] (white) (red) (red) (white) Coaxial digital cord (not supplied) Stereo audio cord (not supplied) to audio input to coaxial digital input to LINE OUT L/R (AUDIO) to DIGITAL OUT (COAXIAL) l: Signal flow B-1 B-2 23 Hookups Connecting to an AV amplifier (receiver) having a Dolby Surround (Pro Logic) decoder and 3 to 6 speakers You can enjoy the Dolby Surround effects only when playing Dolby Surround audio or multi- channel audio (Dolby Digital) discs. If your amplifier (receiver) has L and R audio input jacks only, use . If your amplifier (receiver) has a digital input jack, use . Note When connecting 6 speakers, replace the monaural rear speaker with a center speaker, 2 rear speakers and a subwoofer. C C-1 C-2 CD/DVD player or Front (R) Front (L) Rear (R) Subwoofer l: Signal flow Rear (L) Amplifier (receiver) with Dolby Surround decoder Center Rear (mono) Stereo audio cord (not supplied) [Speakers] Coaxial digital cord (not supplied) (red) (white) to coaxial digital input [Speakers] to audio input (white) (red) to LINE OUT L/R (AUDIO) to DIGITAL OUT (COAXIAL) c continued 24 Connecting to an AV amplifier (receiver) with a digital input jack having a Dolby Digital, MPEG audio or DTS decoder and 6 speakers This connection will allow you to use the Dolby Digital, MPEG audio or DTS decoder function of your AV amplifier (receiver). You are not able to enjoy the surround sound effects of this player. Notes • After you have completed the connection, be sure to set “DOLBY DIGITAL” to “DOLBY DIGITAL” and “DTS” to “ON” in Quick Setup (page 25). Otherwise, no sound or a loud noise will come from the speakers. • For Asian/Oceanian models only If your AV amplifier (receiver) has an MPEG audio decoder function, set “MPEG” to “MPEG” (page 67). Otherwise, no sound or a loud noise will come from the speakers. D Front (R) Front (L) Rear (R) AV amplifier (receiver) having a decoder Subwoofer Center Coaxial digital cord (not supplied) [Speakers] CD/DVD player l: Signal flow [Speakers] Rear (L) to coaxial digital input to DIGITAL OUT (COAXIAL) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 1-6 25 Hookups Step 3: Connecting the Power Cord Plug the player and TV power cords into an AC outlet. Step 4: Quick Setup Follow the steps below to make the minimum number of basic adjustments for using the player. To skip an adjustment, press >. To return to the previous adjustment, press .. The on-screen display differs depending on the player model. 1 Turn on the TV. 2 Press [/1. 3 Switch the input selector on your TV so that the signal from the player appears on the TV screen. “Press [ENTER] to run QUICK SETUP.” appears at the bottom of the screen. If this message does not appear, select “QUICK” under “SETUP” in the Control Bar to run Quick Setup (page 62). 4 Press ENTER without inserting a disc. The Setup Display for selecting the language used in the on-screen display appears. The available languages differ depending on the player model. 5 Press X/x to select a language. The player uses the language selected here to display the menu and subtitles as well. 6 Press ENTER. The Setup Display for selecting the aspect ratio of the TV to be connected appears. LANGUAGE SETUP OSD: MENU: AUDIO: SUBTITLE: FRENCH ENGLISH ENGLISH SPANISH PORTUGUESE SCREEN SETUP TV TYPE: SCREEN SAVER: BACKGROUND: 4:3 PAN SCAN 4:3 LETTER BOX 16:9 4:3 LETTER BOX c continued 26 7 Press X/x to select the setting that matches your TV type. N If you have a 4:3 standard TV • 4:3 LETTER BOX or 4:3 PAN SCAN (page 63) N If you have a wide-screen TV or a 4:3 standard TV with a wide-screen mode • 16:9 (page 63) 8 Press ENTER. The Setup Display for selecting the type of jack used to connect your amplifier (receiver) appears. 9 Press X/x to select the type of jack (if any) you are using to connect to an amplifier (receiver), then press ENTER. Choose the item that matches the audio connection you selected on pages 21 to 24 ( through ). • If you connect just a TV and nothing else, select “NO.” Quick Setup is finished and connections are complete. • Select “LINE OUTPUT L/R (AUDIO).” Quick Setup is finished and connections are complete. • Select “DIGITAL OUTPUT.” The Setup Display for “DOLBY DIGITAL” appears. 10Press X/x to select the type of Dolby Digital signal you wish to send to your amplifier (receiver). Choose the signal that matches the audio connection you selected on pages 22 to 24 ( through ). • D-PCM (page 66) • DOLBY DIGITAL (only if the amplifier (receiver) has a Dolby Digital decoder) (page 66) 11Press ENTER. “DTS” is selected. 12Press X/x to select whether or not you wish to send a DTS signal to your amplifier (receiver). Choose the item that matches the audio connection you selected on pages 22 to 24 ( through ). • OFF (page 67) • ON (only if the amplifier (receiver) has a DTS decoder) (page 67) 13Press ENTER. Quick Setup is finished. All connections and setup operations are complete. For Asian/Oceanian models only: If your AV amplifier (receiver) has an MPEG audio decoder, adjust “MPEG” setting (page 67). YES NO Is this player connected to an amplifier (receiver) ? Select the type of jack you are using. LINE OUTPUT L/R (AUDIO) DIGITAL OUTPUT A D A B-1 C-1 B-2 C-2 D B D AUDIO SETUP AUDIO ATT: AUDIO DRC: DIGITAL OUT: DOLBY DIGITAL: DTS: OFF STANDARD ON DOWNMIX: DOLBY SURROUND DOLBY DIGITAL D-PCM D-PCM B-2 C-2 D AUDIO SETUP AUDIO ATT: AUDIO DRC: DIGITAL OUT: DOLBY DIGITAL: DTS: OFF STANDARD ON DOWNMIX: DOLBY SURROUND D-PCM OFF OFF ON B D B-2 C-2 D 27 Hookups Enjoying the surround sound effects To enjoy the surround sound effects of this player or your amplifier (receiver), set the following items as described below for the audio connection you selected on pages 22 to 24 ( through ). Each of these is the default setting and does not need to be adjusted when you first connect the player. Refer to page 61 for using the Setup Display. Audio Connection (pages 21 to 24) • No additional settings are needed. • Set “DOWNMIX” to “DOLBY SURROUND” (page 66). • If the sound distorts even when the volume is turned down, set “AUDIO ATT” to “ON” (page 65). • Set “DOWNMIX” to “DOLBY SURROUND” (page 66). • Set “DIGITAL OUT” to “ON” (page 66). B D A B-1 C-1 B-2 C-2 D 28 Playing Discs Playing Discs Depending on the DVD or VIDEO CD, some operations may be different or restricted. Refer to the operating instructions supplied with your disc. 1 Turn on your TV. 2 Press [/1. The player turns on and the power indicator lights up in green. 3 Switch the input selector on your TV so that the signal from the player appears on the TV screen. N When using an amplifier (receiver) Turn on the amplifier (receiver) and select the appropriate channel so that you can hear sound from the player. 4 Press A on the player, and place a disc on the disc tray. To place other discs on the tray, press DISC SKIP and place the discs in the order you want to play them. Each time you press DISC SKIP, the disc tray turns so you can place the discs on the empty compartments. The player plays from the last disc placed on the tray. 5 Press H. The disc tray closes, and the player starts playback (continuous play). Adjust the volume on the TV or the amplifier (receiver). Depending on the disc, a menu may appear on the TV screen. For DVDs, see page 33. For VIDEO CDs, see page 33. To turn off the player Press [/1. The player enters standby mode. z Hint The player will turn off automatically whenever you leave it in stop mode for more than 30 minutes (Auto Power Off function). For U.S./Canadian models only: The Auto Power Off function is set to off when you purchase the player. You can turn the function on or off by setting “AUTO POWER OFF” in “CUSTOM SETUP” (page 64). Notes on playing DTS sound tracks on a CD • When playing DTS-encoded CDs, excessive noise will be heard from the analog stereo jacks. To avoid possible damage to the audio system, the consumer should take proper precautions when the analog stereo jacks of the player are connected to an amplification system. To enjoy DTS Digital Surround™ playback, an external 5.1-channel decoder system must A H DISC SKIP Power indicator With the playback side facing down Disc compartment number www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 1-7 29 Playing Discs be connected to the digital jack of the player. • Set the sound to “STEREO” using the AUDIO button when you play DTS sound tracks on a CD (page 46). • Do not play DTS sound tracks without first connecting the player to an audio component having a built-in DTS decoder. The player outputs the DTS signal via the DIGITAL OUT (COAXIAL) jack even if “DTS” in “AUDIO SETUP” is set to “OFF” in the Setup Display (page 67), and may affect your ears or cause your speakers to be damaged. Notes on playing DVDs with a DTS sound track • DTS audio signals are output only through the DIGITAL OUT (COAXIAL) jack. • When you play a DVD with DTS sound tracks, set “DTS” to “ON” in “AUDIO SETUP” (page 67). • If you connect the player to audio equipment without a DTS decoder, do not set “DTS” to “ON” in “AUDIO SETUP” (page 67). A loud noise may come out from the speakers, affecting your ears or causing the speakers to be damaged. Additional operations To Operation Select a disc Press DISC SELECT 1–5 on the player Stop Press x Pause Press X Resume play after pause Press X or H Go to the next disc Press DISC SKIP Go to the next chapter, track, or scene in continuous play mode Press > Go back to the previous chapter, track, or scene in continuous play mode Press . Stop play and remove the disc Press Z Replay the previous scene (DVD only) Press REPLAY Check if a disc is in the disc compartment Press LOAD on the player. The disc number indicators on the front panel display (1–5) light up. A H X x ./> DISC SKIP DISC SELECT LOAD c continued 30 z Hints • The Replay function is useful when you want to review a scene or dialog that you missed. • Before loading the discs, a disc number indicator of an empty compartment may be lit. Note You may not be able to use the Replay function with some scenes. Replacing discs while playing a disc (EXCHANGE) You can open the disc tray while playing a disc so that you can check which discs are to be played next and replace discs without interrupting playback of the current disc. 1 Press EXCHANGE. The disc tray opens and two disc compartments appear. Even if the player is playing a disc, it doesn’t stop playing. 2 Replace the discs in the compartments with new ones. 3 Press DISC SKIP. The disc tray turns and another two disc compartments appear. 4 Replace the discs in the compartments with new ones. 5 Press EXCHANGE. The disc tray closes. z Hint While the disc tray is open, – If the playback of the current disc end, the player stops playing. If the disc is played in One Disc Repeat Play mode (page 40), the current disc starts playing again. – In All Discs Shuffle Play mode (page 39), titles/ tracks/chapters are reshuffled only on the current disc. – In Program Play mode (page 37), the titles/tracks/ chapters only on the current disc are played. Note Do not push the disc tray to close in Step 5, as you may damage the player. Locking the disc tray (Child Lock) You can lock the disc tray to prevent children from opening it. When the player is in standby mode, press O RETURN, ENTER, and then [/1 on the remote. The player turns on and “LOCKED” appears on the front panel display. The A and EXCHANGE buttons on the player and the Z button on the remote do not work while the Child Lock is set. To unlock the disc tray When the player is in standby mode, press O RETURN, ENTER, and then [/1 again. Note Even if you select “RESET” under “SETUP” in the Control Bar (page 61), the disc tray remains locked. DISC SKIP EXCHANGE 31 Playing Discs Searching for a Particular Point on a Disc (Scan, Slow-motion Play, Search, Freeze Frame) You can quickly locate a particular point on a disc by monitoring the picture or playing back slowly. Note Depending on the DVD/VIDEO CD, you may not be able to do some of the operations described. Locating a point quickly by playing a disc in fast forward or fast reverse (Scan) Press m or M while playing a disc. When you find the point you want, press H to return to normal speed. Each time you press m or M during scan, the playback speed changes. Three speeds are available. With each press the indication changes as follows: Playback direction Opposite direction The “×2B”/“× 2b” playback speed is about twice the normal speed. The “2M”/“2m” playback speed is faster than “1M”/ “1m.” Watching frame by frame (Slow- motion play) Press m or M when the player is in pause mode. To return to the normal speed, press H. Each time you press m or M during Slow-motion play, the playback speed changes. Two speeds are available. With each press the indication changes as follows: Playback direction 2 y 1 Opposite direction (DVD only) 2 y 1 The “2 y”/“2 ” playback speed is slower than “1 y”/“1 .” × 2B (DVD/CD only) t 1M t 2M × 2b (DVD only) t 1m t 2m 32 Resuming Playback from the Point Where You Stopped the Disc (Resume Play/Multi-disc Resume) The player remembers the point where you stopped the disc. Resuming playback for the current disc (Resume Play) The player remembers the point where you stopped the disc even if the player enters standby mode by pressing [/1. 1 While playing a disc, press x to stop playback. “RESUME” appears on the front panel display. 2 Press H. The player starts playback from the point where you stopped the disc in Step 1. z Hint To play from the beginning of the disc, press x twice, then press H. Notes • The point where you stopped playing is cleared when: – you change the play mode. – you do Program Play or Shuffle Play. – you change the settings on the Setup Display. • When playing a CD, the point where you stopped is cleared when the disc tray is opened or the power cord is disconnected. • When playing a DATA CD, the point where you stopped playing is cleared when the player enters standby mode, the disc tray is opened, or the power cord is disconnected. • This function may not work with some discs. Storing the point where you stopped the disc (Multi-disc Resume) The player stores the point where you stopped the disc and resumes playback from the same point the next time you insert the same disc. The player remembers the stopped point of the disc even after you play other discs in the disc tray. Resume playback points for up to 6 different DVD/VIDEO discs remain in memory even if you disconnect the power cord. When you store a resume playback point for the 7th disc, the resume playback point for the first disc is deleted. z Hints • To play from the beginning of the disc, press x twice, then press H. • To turn off the Multi-disc Resume function, set “MULTI-DISC RESUME” in “CUSTOM SETUP” to “OFF” (page 65). Playback restarts at the resume point only for the current disc in the player. Note This function may not work with some discs. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 1-8 33 Playing Discs Using the DVD’s Menu A DVD is divided into long sections of a picture or a music feature called “titles.” When you play a DVD which contains several titles, you can select the title you want using the TOP MENU button. When you play DVDs that allow you to select items such as the language for the subtitles and the language for the sound, select these items using the MENU button. 1 Press TOP MENU or MENU. The disc’s menu appears on the TV screen. The contents of the menu vary from disc to disc. 2 Press C/X/x/c or the number buttons to select the item you want to play or change. 3 Press ENTER. Playing VIDEO CDs with PBC Functions (PBC Playback) PBC (Playback Control) allows you to play VIDEO CDs interactively by following the menu on the TV screen. 1 Start playing a VIDEO CD with PBC functions. The menu for your selection appears. 2 Select the item number and track you want using X/x or the number buttons. 3 Press ENTER. 4 Follow the instructions in the menu for interactive operations. Refer to the instructions supplied with the disc, as the operating procedure may differ depending on the VIDEO CD. To return to the menu Press O RETURN. Number buttons Number buttons c continued 34 z Hint To play without using PBC, press ./> while the player is stopped to select a track, then press H or ENTER. “Play without PBC.” appears on the TV screen and the player starts continuous play. You cannot play still pictures such as a menu. To return to PBC playback, press x twice then press H. Notes • Depending on the VIDEO CD, “Press ENTER” in Step 3 may appear as “Press SELECT” in the instructions supplied with the disc. In this case, press H. • The PBC functions of Super VCDs do not work with this player. Super VCDs are played in continuous play mode only. Playing an MP3 Audio Track You can play back DATA CDs (CD-ROMs/ CD-Rs/CD-RWs) recorded in MP3 (MPEG1 Audio Layer 3) format. 1 Press Z and place a DATA CD on the disc tray. 2 Press H. The disc tray closes, and the player starts to play the first MP3 audio track in the first album on the disc. Notes • The playback order may be different from the edited order. See “The playback order of MP3 audio tracks” below for details. • This player can play MP3 audio tracks recorded in the following sampling frequencies: 32 kHz, 44.1 kHz, 48 kHz. 35 Playing Discs Selecting an album and track 1 Press MENU. The list of MP3 albums recorded on the DATA CD appears. 2 Select an album using X/x and press ENTER. The list of tracks contained in the album appears. 3 Select a track using X/x and press ENTER. The selected track starts playing. When a track or album is being played, its title is shaded. To go to the next or previous page Press c or C. To return to the previous display Press O RETURN. To turn off the display Press MENU. Notes • Only the letters in the alphabet and numbers can be used for album or track names. Anything else is displayed as an asterisk. • ID3 tags cannot be displayed. About MP3 audio tracks You can play MP3 audio tracks on CD- ROMs, CD-Rs, or CD-RWs. However, the discs must be recorded according to ISO9660 level 1, level 2, or Joliet format for the player to recognize the tracks. You can also play discs recorded in Multi Session. See the instructions of the CD-R/RW device or recording software (not supplied) for details on the recording format. To play a Multi Session CD This player can play Multi Session CDs when an MP3 audio track is located in the first session. Any subsequent MP3 audio tracks, recorded in the later sessions, can also be played back. When audio tracks and images in music CD format or Video CD format are recorded in the first session, only the first session will be played back. Notes • If you put the extension “.MP3” to data not in MP3 format, the player cannot recognize the data properly and will generate a loud noise which could damage your speaker system. • The player cannot play audio tracks in MP3PRO format. 1 ( 3 0 ) R O C K B E S T H I T K A R A O K E J A Z Z R & B M Y F A V O R I T E S O N G S C L A S S I C A L S A L S A O F C U B A B O S S A N O V A J A Z Z 1 ( 90 ) 0 1 S H E I S S P E C I A L 0 2 A L L Y O U N E E D I S . . . 0 3 S P I C Y L I F E 0 4 H A P P Y H O U R 0 5 R I V E R S I D E 0 6 5 0 7 T A K E T I M E , T A K E T I M E c continued 36 The playback order of MP3 audio tracks The playback order of albums and tracks recorded on a DATA CD is as follows. NStructure of disc contents When you insert a DATA CD and press H, the numbered tracks are played sequentially, from 1 through 7. Any sub-albums/tracks contained within a currently selected album take priority over the next album in the same tree. (Example: C contains D so 4 is played before 5.) When you press MENU and the list of MP3 albums appears (page 35), the albums are arranged in the following order: A t B t C t D t F t G. Albums that do not contain tracks (such as album E) do not appear in the list. z Hints • If you add numbers (01, 02, 03, etc.) to the front of the track names, the tracks will be played in that order. • Since a disc with many trees takes longer to start playback, place your albums within the first two trees. Notes • Depending on the software you use to create the DATA CD, the playback order may differ from the illustration above. • The playback order above may not be applicable if there are more than a total of 200 albums and tracks in the DATA CD. • The player can recognize up to 100 albums (the player will count just albums, including albums that do not contain MP3 audio tracks). The player will not play any albums beyond the first 100 albums. Of the first 100 albums, the player will play no more than a combined total of 200 albums and tracks. ROOT Tree 1 Tree 2 Tree 3 Tree 4 Tree 5 album track www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 1-9 37 Playing Discs Various Play Mode Functions (Program Play, Shuffle Play, Repeat Play, A-B Repeat Play) You can set the following play modes: • Program Play (page 37) • Shuffle Play (page 39) • Repeat Play (page 40) • A-B Repeat Play (page 41) Note The play mode is canceled when: – you open the disc tray. – the player enters standby mode by pressing [/1. Selecting the disc mode (One Disc or All Discs) You can play one disc or all of the discs in the player. Before setting Program Play, Shuffle Play, or Repeat Play, you must select whether to set those play mode on one disc or all of the discs. 1 Press DISPLAY during playback (or twice during stop mode). The following Control Bar appears. 2 Press ENTER to select the disc mode. (One Disc) or (All Discs) is selected alternately. Creating your own program (Program Play) You can play the contents of a disc in the order you want by arranging the order of the titles, chapters, or tracks on the disc to create your own program. You can program up to 99 items. By selecting All Discs mode (page 37), you can create a program for all of the discs in the player. 1 Press DISPLAY twice while the player is in stop mode. The following Control Bar appears. Disc mode Number buttons c continued 38 2 Press C/c to select (PROGRAM), then press ENTER. The display for programming appears. 3 Press c. The player is ready to program the first disc. 4 Select the disc you want to program using the number buttons or X/x, then press ENTER. The cursor moves to the title or track row “T” (in this case, “01”). 5 Select the title, chapter, or track you want to program. N When playing a DVD For example, select chapter “03” of title “02.” Press X/x or the number buttons to select “02” under “T,” then press ENTER. Next, press X/x or the number buttons to select “03” under “C,” then press ENTER. N When playing a VIDEO CD or CD For example, select track “02.” Press X/x or the number buttons to select “02” under “T,” then press ENTER. 6 To program other discs, titles, chapters, or tracks, repeat Steps 3 to 5. The programmed discs, titles, chapters, and tracks are displayed in the selected order. 7 Press H to start Program Play. Program Play begins. When the program ends, you can restart the same program again by pressing H. PROGRAM – : – – – – 1. – – – – – ALL CLEAR 2. – – – – – 3. – – – – – 4. – – – – – 5. – – – – – 6. – – – – – T ALL PROGRAM – : – – – – 1. – – – – – ALL CLEAR 2. – – – – – 3. – – – – – 4. – – – – – 5. – – – – – 6. – – – – – T ALL 2. – – – – – 3. – – – – – 4. – – – – – 5. – – – – – 6. – – – – – C ALL 01 02 03 04 05 01 02 03 04 05 06 06 PROGRAM 3 : DVD 1. – – – – – ALL CLEAR T ALL Chapters recorded on a disc Titles or tracks recorded on a disc Disc type “?” appears when the player has not played the disc. 2. – – – – – 3. – – – – – 4. – – – – – 5. – – – – – 6. – – – – – C ALL 01 02 03 04 05 01 02 03 04 05 06 06 PROGRAM 3 : DVD 1. – – – – – ALL CLEAR T ALL 1. 3DVD –T02–C03 PROGRAM – : – – – – ALL CLEAR T ALL 2. – – – – – 3. – – – – – 4. – – – – – 5. – – – – – 6. – – – – – Selected disc, title and chapter 1. 3DVD –T02–C03 PROGRAM – : – – – – ALL CLEAR T ALL 2. 2VCD –T02 3. – – – – – 4. – – – – – 5. – – – – – 6. – – – – – 0:15:30 Selected disc and track 39 Playing Discs To stop Program Play Press CLEAR. To turn off the display Press DISPLAY repeatedly until the display is turned off. To cancel or change a program 1 Follow Steps 1 and 2 of “Creating your own program (Program Play).” 2 Select the program number of the disc, title, chapter, or track you want to cancel or change using X/x or the number buttons, and press c. 3 To cancel the program, press C then CLEAR. To change the program, follow Step 4 for new programming. To cancel all the discs, titles, chapters, or tracks in the program 1 Follow Steps 1 and 2 of “Creating your own program (Program Play).” 2 Press X and select “ALL CLEAR.” 3 Press ENTER. z Hint You can do Repeat Play or Shuffle Play of the programmed titles, chapters, or tracks. During Program Play, follow the steps of “Repeat Play” (page 40) or “Shuffle Play” (page 39). Notes • When playing Super VCDs, the total time of the programmed tracks does not appear on the screen. • You cannot use this function with DATA CDs. Playing in random order (Shuffle Play) You can have the player “shuffle” titles, chapters, or tracks. Subsequent “shuffling” may produce a different playing order. By selecting All Discs mode (page 37), you can shuffle all of the discs in the player. 1 Press DISPLAY during playback. The following Control Bar appears. 2 Press C/c to select (SHUFFLE), then press ENTER repeatedly to select the item to be shuffled. N When playing a DVD • DISC* • TITLE • CHAPTER N When playing a VIDEO CD or CD • DISC* • TRACK N When playing a DATA CD • DISC* TITLE c continued 40 N When Program Play is activated • ON: shuffles titles, chapters, or tracks selected in Program Play. * You can select “DISC” in All Discs mode only. To return to normal play Press CLEAR, or select “OFF” in Step 2. To turn off the Control Bar Press DISPLAY repeatedly until the Control Bar is turned off. z Hints • You can set Shuffle Play while the player is stopped. After selecting the “SHUFFLE” option, press H. Shuffle Play starts. • Up to 96 chapters in a disc can be played in random order when “CHAPTER” is selected. Playing repeatedly (Repeat Play) You can play all of the titles, albums or tracks on a disc or a single title, chapter, album, or track repeatedly. You can use a combination of Shuffle or Program Play modes. By selecting All Discs mode (page 37), you can repeat all of the discs in the player. 1 Press DISPLAY during playback. The following Control Bar appears. 2 Press C/c to select (REPEAT), then press ENTER repeatedly to select the item to be repeated. N When playing a DVD • DISC: repeats all of the titles on the current disc in One Disc mode, or all of the discs in All Discs mode. • TITLE: repeats the current title on a disc. • CHAPTER: repeats the current chapter. CHAPTER www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 1-10 41 Playing Discs N When playing a VIDEO CD or CD • DISC: repeats all of the tracks on the current disc in One Disc mode, or all of the discs in All Discs mode. • TRACK: repeats the current track. N When playing a DATA CD (MP3 audio) • DISC: repeats all of the albums on the current disc in One Disc mode, or all of the discs in All Discs mode. • ALBUM: repeats the current album. • TRACK: repeats the current track. N When Program Play or Shuffle Play is activated • ON: repeats Program Play or Shuffle Play. To return to normal play Press CLEAR, or select “OFF” in Step 2. To turn off the Control Bar Press DISPLAY repeatedly until the Control Bar is turned off. z Hints • You can set Repeat Play while the player is stopped. After selecting the “REPEAT” option, press H. Repeat Play starts. • You can select “REPEAT” directly by pressing REPEAT. Repeating a specific portion (A- B Repeat Play) You can play a specific portion of a title, chapter or track repeatedly. (This function is useful when you want to memorize lyrics, etc.) 1 Press DISPLAY during playback. The following Control Bar appears. 2 Press C/c to select (A-B REPEAT). 3 During playback, when you find the starting point (point A) of the portion to be played repeatedly, press ENTER. The starting point (point A) is set. 4 When you reach the ending point (point B), press ENTER again. The set points are displayed and the player starts repeating this specific portion. A13 – 0:27:34 B c continued 42 To return to normal play Press CLEAR. To turn off the Control Bar Press DISPLAY repeatedly until the Control Bar is turned off. Note When you set A-B Repeat Play, the settings for Shuffle Play, Repeat Play, and Program Play are canceled. 43 Searching for a Scene Searching for a Scene Searching for a Title/ Chapter/Track/Index/ Scene (Search mode) You can search a DVD by title or chapter, and you can search a VIDEO CD/CD by track, index, or scene. As titles and tracks are assigned unique numbers on the disc, you can select the desired one by entering its number. Or, you can search for a scene using the time code. 1 Press SEARCH MODE. The following display appears. “-- (**)” appears next to the icon (** refers to a number). The number in parentheses indicates the total number of titles, tracks, indexes, scenes, etc. of the disc. 2 Press SEARCH MODE repeatedly to select the search method. N When playing a DVD (TITLE), (CHAPTER), (TIME/TEXT) Select “TIME/TEXT” to search for a starting point by inputting the time code. N When playing a VIDEO CD (TRACK) or (INDEX) N When playing a VIDEO CD with PBC Playback (SCENE) or (INDEX) N When playing a CD (TRACK) or (INDEX) N When playing a DATA CD (MP3 audio) (ALBUM) or (TRACK) 3 Select the number of the title, track, scene, time code, etc. you want using the number buttons. For example, to find the scene at 2 hours, 10 minutes, and 20 seconds after the beginning, select “TIME/TEXT” in Step 2 and enter “2:10:20.” If you make a mistake Cancel the number by pressing CLEAR, then select another number. 4 Press ENTER. The player starts playback from the selected number. z Hint When the display is turned off, you can search for a chapter (DVD) or track (CD) by pressing the number buttons and ENTER. Number buttons – – (10) 44 Viewing Information About the Disc Checking the Playing Time and Remaining Time You can check the playing time and remaining time of the current title, chapter, or track. Also, you can check the DVD/CD text or track name (MP3 audio) recorded on the disc. 1 Press DISPLAY repeatedly during playback until (TIME/TEXT) appears. 2 Press ENTER repeatedly to change the time information. The display and the kinds of time that you can change depend on the disc you are playing. N When playing a DVD • T **:**:** Playing time of the current title • T–**:**:** Remaining time of the current title • C **:**:** Playing time of the current chapter • C–**:**:** Remaining time of the current chapter N When playing a VIDEO CD (with PBC functions) • **:** Playing time of the current scene N When playing a VIDEO CD (without PBC functions) or CD • T **:** Playing time of the current track • T–**:** Remaining time of the current track • D **:** Playing time of the current disc • D–**:** Remaining time of the current disc N When playing a DATA CD (MP3 audio) • ****:** Playing time of the current track N When playing a Super VCD (For Asian/ Oceanian models only) • T **:** Playing time of the current track To turn off the Control Bar Press DISPLAY repeatedly until the Control Bar is turned off. To check the DVD/CD text or track name (MP3 audio) Press ENTER repeatedly in Step 2 to display text recorded on the DVD/CD/DATA CD. The DVD/CD text appears only when text is recorded in the disc. You cannot change the text. If the disc does not contain text, “NO TEXT” appears. For DATA CDs, only the track name of the MP3 audio track appears. T41 – 8 3:DVD T 1:01:57 Time information Title, track (CD/ VIDEO CD), scene, or album number Chapter, index, or track (DATA CD) Disc number and type BRAHMS SYMPHONY www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 1-11 45 Viewing Information About the Disc Checking the information on the front panel display You can view the time information and text displayed on the TV screen also on the front panel display. The information on the front panel display changes as follows when you change the time information on your TV screen. When playing a DVD When playing a VIDEO CD (without PBC functions) or CD When playing a DATA CD (MP3 audio) z Hints • When playing VIDEO CDs with PBC functions, the disc number, scene number and the playing time are displayed. • Long text that does not fit in a single line will scroll across the front panel display. • You can also check the time information and text by pressing TIME/TEXT repeatedly. Notes • Depending on the type of disc being played, the DVD/CD text or track name may not be displayed. • The player can only display the first level of the DVD/CD text, such as the disc name or title. • Playing time of MP3 audio tracks may not be displayed correctly. Title playing time and current disc, title and chapter number Remaining time of the current title Playing time and number of the current chapter Remaining time of the current chapter Text Track playing time and current disc, track and index number Remaining time of the current track Remaining time of the disc Text Playing time of the disc Track name Track playing time and number of the current disc, album and track 46 Sound Adjustments Changing the Sound When playing a DVD recorded in multiple audio formats (PCM, Dolby Digital, MPEG audio, or DTS), you can change the audio format. If the DVD is recorded with multilingual tracks, you can also change the language. With CDs, DATA CDs, or VIDEO CDs, you can select the sound from the right or left channel and listen to the sound of the selected channel through both the right and left speakers. For example, when playing a disc containing a song with the vocals on the right channel and the instruments on the left channel, you can hear the instruments from both speakers by selecting the left channel. 1 Press AUDIO during playback. The following display appears. The number in parentheses indicates the total number of available audio signals. 2 Press AUDIO repeatedly to select the desired audio signal. N When playing a DVD Depending on the DVD, the choice of language varies. When 4 digits are displayed, they indicate a language code. Refer to “Language Code List” on page 74 to see which language the code represents. When the same language is displayed two or more times, the DVD is recorded in multiple audio formats. N When playing a VIDEO CD, CD, or DATA CD (MP3 audio) The default setting is underlined. • STEREO: The standard stereo sound • 1/L: The sound of the left channel (monaural) • 2/R: The sound of the right channel (monaural) N When playing a Super VCD (For Asian/ Oceanian models only) The default setting is underlined. • 1:STEREO: The stereo sound of the audio track 1 • 1:1/L: The sound of the left channel of the audio track 1 (monaural) • 1:2/R: The sound of the right channel of the audio track 1 (monaural) • 2:STEREO: The stereo sound of the audio track 2 • 2:1/L: The sound of the left channel of the audio track 2 (monaural) • 2:2/R: The sound of the right channel of the audio track 2 (monaural) Note While playing a Super VCD on which the audio track 2 is not recorded, no sound will come out when you select “2:STEREO,” “2:1/L” or “2:2/R.” AUDIO DISPLAY 1(4): ENGLISH 47 Sound Adjustments Checking the audio signal format If you press DISPLAY repeatedly during playback, the format of the current audio signal (Dolby Digital, MPEG audio, DTS, PCM, etc.) appears as shown below. Example: Dolby Digital 5.1 ch About audio signals Audio signals recorded in a disc contain the sound elements (channels) shown below. Each channel is output from a separate speaker. • Front (L) • Front (R) • Center • Rear (L) • Rear (R) • Rear (Monaural): This signal can be either the Dolby Surround Sound processed signals or the Dolby Digital sound’s monaural rear audio signals. • LFE (Low Frequency Effect) signal Note If “DTS” is set to “OFF” in “AUDIO SETUP,” the DTS track selection option will not appear on the screen even if the disc contains DTS tracks (page 67). TV Virtual Surround Settings (TVS) When you connect a stereo TV or 2 front speakers, TVS (TV Virtual Surround) lets you enjoy surround sound effects by using sound imaging to create virtual rear speakers from the sound of the front speakers (L: left, R: right) without using actual rear speakers. TVS was developed by Sony to produce surround sound for home use using just a stereo TV. This function is designed to work with the LINE OUT L/R (AUDIO) jacks. Note that if you select one of the TVS settings, the player does not output the following signals from the DIGITAL OUT (COAXIAL) jack. —Dolby Digital signals when you set “DOLBY DIGITAL” in “AUDIO SETUP” to “D-PCM” (page 66) —MPEG audio signals 1 Press DISPLAY twice during playback. The following Control Bar appears. 3 / 2 .1 DOLBY DIGITAL Rear (L/R) Front (L/R) + Center LFE (Low Frequency Effect) c continued 48 2 Press C/c to select (SURROUND), then press ENTER repeatedly to select one of the TVS sounds. Refer to the following explanations given for each item. • TVS DYNAMIC • TVS WIDE • TVS NIGHT • TVS STANDARD To cancel the setting Select “OFF” in Step 2. To turn off the Control Bar Press DISPLAY repeatedly until the Control Bar is turned off. NTVS DYNAMIC Creates virtual rear speakers from the sound of the front speakers (L, R) without using actual rear speakers (shown below). This mode is effective when the distance between the front L and R speakers is short, such as with built-in speakers on a stereo TV. NTVS WIDE Creates virtual rear speakers from the sound of the front speakers (L, R) without using actual rear speakers. The virtual speakers are reproduced as shown in the illustration below. This mode is effective when the distance between the front L and R speakers is short, such as with built-in speakers on a stereo TV. NTVS NIGHT Large sounds, such as explosions, are suppressed, but the quieter sounds are unaffected. This feature is useful when you want to hear the dialog and enjoy the surround sound effects of “TVS WIDE” at low volume. NTVS STANDARD Creates virtual rear speakers from the sound of the front speakers (L, R) without using actual rear speakers. The virtual speakers are reproduced as shown in the illustration below. Use this setting when you want to use TVS with 2 separate speakers. z Hint You can also change the setting by pressing SUR (or SURROUND on the player) repeatedly. Notes • When the playing signal does not contain a signal for the rear speakers, the surround effects will be difficult to hear. • When you select one of the TVS modes, turn off the surround setting of the connected TV or amplifier (receiver). • Make sure that your listening position is between and at an equal distance from your speakers, and that the speakers are located in similar surroundings. TVS DYNAMIC TV L : Front speaker (left) R : Front speaker (right) : Virtual speaker TV L R www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 1-12 49 Sound Adjustments • “TVS NIGHT” only works with Dolby Digital and MPEG audio discs. However, not all discs will respond to the “TVS NIGHT” function in the same way. • If you use the DIGITAL OUT (COAXIAL) jack and set “DOLBY DIGITAL” to “DOLBY DIGITAL” or “DTS” to “ON” in “AUDIO SETUP,” sound will come from your speakers but it will not have the TVS effect. 50 Enjoying Movies Changing the Angles If various angles (multi-angles) for a scene are recorded on the DVD, “ANGLE” appears in the front panel display. This means that you can change the viewing angle. 1 Press ANGLE during playback. The number of the angle appears on the display. The number in parentheses indicates the total number of angles. 2 Press ANGLE repeatedly to select the angle number. The scene changes to the selected angle. Note Depending on the DVD, you may not be able to change the angles even if multi-angles are recorded on the DVD. Displaying the Subtitles If subtitles are recorded on the discs, you can change the subtitles or turn them on and off whenever you want while playing a DVD. 1 Press SUBTITLE during playback. The following display appears. The number in parentheses indicates the total number of available subtitles. 2 Press SUBTITLE repeatedly to select the language. Depending on the DVD, the choice of language varies. When 4 digits are displayed, they indicate a language code. Refer to “Language Code List” on page 74 to see which language the code represents. ANGLE 2(7) SUBTITLE 1(8):ENGLISH 51 Enjoying Movies To turn off the subtitles Select “OFF” in Step 2. Note Depending on the DVD, you may not be able to change the subtitles even if multilingual subtitles are recorded on it. You also may not be able to turn them off. Adjusting the Picture Quality (BNR) The Block Noise Reduction (BNR) function adjusts the picture quality by reducing the “block noise” or mosaic like patterns that appear on your TV screen. 1 Press DISPLAY twice during playback. The following Control Bar appears. 2 Press C/c to select (BNR), then press ENTER repeatedly to select a level. • 1: reduces the “block noise.” • 2: reduces the “block noise” more than 1. • 3: reduces the “block noise” more than 2. 1 c continued 52 To cancel the “BNR” setting Select “OFF” in Step 2. To turn off the Control Bar Press DISPLAY repeatedly until the Control Bar is turned off. Notes • If the outlines of the images on your screen should become blurred, set “BNR” to “OFF.” • Depending on the disc or the scene being played, the “BNR” effect may be hard to discern. Adjusting the Playback Picture (CUSTOM PICTURE MODE) You can adjust the video signal of the DVD or VIDEO CD from the player to obtain the picture quality you want. Choose the setting that best suits the program you are watching. 1 Press DISPLAY twice during playback. The following Control Bar appears. 2 Press C/c to select (CUSTOM PICTURE MODE), then press ENTER repeatedly to select the setting you want. The default setting is underlined. • STANDARD: displays a standard picture. • DYNAMIC 1: produces a bold dynamic picture by increasing the picture contrast and the color intensity. DYNAMIC 1 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 1-13 55 Using Various Additional Functions Using Various Additional Functions Locking Discs (CUSTOM PARENTAL CONTROL, PARENTAL CONTROL) You can set two kinds of playback restrictions for the desired disc. • Custom Parental Control You can set playback restrictions so that the player will not play inappropriate discs. • Parental Control Playback of some DVDs can be limited according to a predetermined level such as the age of the users. Scenes may be blocked or replaced with different scenes. The same password is used for both Parental Control and Custom Parental Control. Custom Parental Control You can set the same Custom Parental Control password for up to 40 discs. When you set the 41st-disc, the first disc is canceled. 1 Insert the disc you want to lock. If the disc is playing, press x to stop playback. 2 Press DISPLAY while the player is in stop mode. The following Control Bar appears. 3 Press X/x to select (PARENTAL CONTROL), then press ENTER. The options for “PARENTAL CONTROL” appear. 4 Press X/x to select “ON t,” then press ENTER. N If you have not entered a password The display for registering a new password appears. Enter a 4-digit password using the number buttons, then press ENTER. The display for confirming the password appears. N When you have already registered a password The display for entering the password appears. Number buttons QUICK ON PLAYER PASSWORD OFF PARENTAL CONTROL Enter a new 4-digit password, then press . ENTER PARENTAL CONTROL Enter password, then press . ENTER c continued 53 Enjoying Movies • DYNAMIC 2: produces a more dynamic picture than DYNAMIC 1 by further increasing the picture contrast and the color intensity. • CINEMA 1: enhances details in dark areas by increasing the black level. • CINEMA 2: White colors become brighter and black colors become richer, and the color contrast is increased. To turn off the Control Bar Press DISPLAY repeatedly until the Control Bar is turned off. z Hints • When you watch a movie, “CINEMA 1” or “CINEMA 2” is recommended. • You can also select the “CUSTOM PICTURE MODE” setting by pressing PICTURE MODE repeatedly. Enhancing the Playback Picture (DIGITAL VIDEO ENHANCER) The Digital Video Enhancer (DVE) function makes the picture appear clear and crisp by enhancing the outlines of images on your TV screen. Also, this function can soften the images on the screen. 1 Press DISPLAY twice during playback. The following Control Bar appears. 2 Press C/c to select (DIGITAL VIDEO ENHANCER), then press ENTER repeatedly to select a level. • 1: enhances the outline. • 2: enhances the outline more than 1. • 3: enhances the outline more than 2. • SOFT: softens the image (DVD only). ENTER DISPLAY 1 c continued 54 To cancel the “DIGITAL VIDEO ENHANCER” setting Select “OFF” in Step 2. To turn off the Control Bar Press DISPLAY repeatedly until the Control Bar is turned off. Note Depending on the disc or the scene being played, noise found in the disc may become more apparent. If this happens, it is recommended that you use the BNR function (page 51) with the DVE function. If the condition still does not improve, reduce the Digital Video Enhancer level, or select “SOFT” (DVD only) in Step 2 above. 56 5 Enter or re-enter your 4-digit password using the number buttons, then press ENTER. “Custom parental control is set.” appears when you enter your password. To turn off the Custom Parental Control function 1 Follow Steps 1 through 3 of “Custom Parental Control.” 2 Press X/x to select “OFF t,” then press ENTER. 3 Enter your 4-digit password using the number buttons, then press ENTER. To play a disc for which Custom Parental Control is set 1 Insert the disc for which Custom Parental Control is set. The “CUSTOM PARENTAL CONTROL” display appears. 2 Enter your 4-digit password using the number buttons, then press ENTER. The player is ready for playback. z Hint If you forget your password, enter the 6-digit number “199703” using the number buttons when the “CUSTOM PARENTAL CONTROL” display asks you for your password, then press ENTER. The display will ask you to enter a new 4-digit password. Parental Control (limited playback) Playback of some DVDs can be limited according to a predetermined level such as the age of the users. The “PARENTAL CONTROL” function allows you to set a playback limitation level. 1 Press DISPLAY while the player is in stop mode. The following Control Bar appears. 2 Press X/x to select (PARENTAL CONTROL), then press ENTER. The options for “PARENTAL CONTROL” appear. CUSTOM PARENTAL CONTROL Custom parental control is already set. To play, enter your password and press . ENTER Number buttons QUICK ON PLAYER PASSWORD OFF www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 1-14 58 To play a disc for which Parental Control is set 1 Insert the disc and press H. The display for entering your password appears. 2 Enter your 4-digit password using the number buttons, then press ENTER. The player starts playback. z Hint If you forget your password, remove the disc and repeat Steps 1 to 3 of “Parental Control (limited playback).” When you are asked to enter your password, enter “199703” using the number buttons, then press ENTER. The display will ask you to enter a new 4-digit password. After you enter a new 4-digit password in Step 4, replace the disc in the player and press H. When the display for entering your password appears, enter your new password. Note When you play DVDs which do not have the Parental Control function, playback cannot be limited on this player. Area Code Changing the password 1 Press DISPLAY while the player is in stop mode. The Control Bar appears. 2 Press X/x to select (PARENTAL CONTROL), then press ENTER. The options for “PARENTAL CONTROL” appear. 3 Press X/x to select “PASSWORD t,” then press ENTER. The display for entering the password appears. 4 Enter your 4-digit password using the number buttons, then press ENTER. 5 Enter a new 4-digit password using the number buttons, then press ENTER. 6 To confirm your password, re-enter it using the number buttons, then press ENTER. Standard Code number Argentina 2044 Australia 2047 Austria 2046 Belgium 2057 Brazil 2070 Canada 2079 Chile 2090 China 2092 Denmark 2115 Finland 2165 France 2174 Germany 2109 India 2248 Indonesia 2238 Italy 2254 Japan 2276 Korea 2304 Malaysia 2363 Mexico 2362 Netherlands 2376 New Zealand 2390 Norway 2379 Pakistan 2427 Philippines 2424 Portugal 2436 Russia 2489 Singapore 2501 Spain 2149 Sweden 2499 Switzerland 2086 Thailand 2528 United Kingdom 2184 Standard Code number 59 Using Various Additional Functions If you make a mistake entering your password Press C before you press ENTER and input the correct number. If you make a mistake Press O RETURN. To turn off the display Press DISPLAY repeatedly until the display is turned off. Controlling Your TV with the Supplied Remote You can control the sound level, input source, and power switch of your Sony TV with the supplied remote. You can control your TV using the buttons below. Note Depending on the unit being connected, you may not be able to control your TV using some of the buttons. By pressing You can TV [/1 Turn the TV on or off VOL +/– Adjust the volume of the TV TV/VIDEO Switch the TV’s input source between the TV and other input sources Number buttons c continued 60 Controlling other TVs with the remote You can control the sound level, input source, and power switch of non-Sony TVs as well. If your TV is listed in the table below, set the appropriate manufacturer’s code. 1 While holding down TV [/1, press the number buttons to select your TV’s manufacturer’s code (see the table below). 2 Release TV [/1. Checking the model name of your remote The supplied remote commander is different depending on the player model. Check the model name of your remote (RMT-D143A or RMT-D143E) so that you can input the correct manufacturer’s code number to your remote. Code numbers of controllable TVs If more than one code number is listed, try entering them one at a time until you find the one that works with your TV. NFor U.S./Canadian models (RMT-D143A) NFor Asian/Oceanian models (RMT-D143E) Notes • If you enter a new code number, the code number previously entered will be erased. • When you replace the batteries of the remote, the code number you have set may be reset to the default setting. Set the appropriate code number again. Model name Manufacturer Code number Sony (default) 01 JVC 09 Panasonic 19 Philips 21 RCA 10 Samsung 20 Sanyo 11 Sharp 18 Toshiba 07 Zenith 15 Manufacturer Code number Sony (default) 01 JVC 33 LG 06 Panasonic 17, 49 Philips 06, 08 Samsung 23 Sharp 29 Toshiba 38 57 Using Various Additional Functions 3 Press X/x to select “PLAYER t,” then press ENTER. N If you have not entered a password The display for registering a new password appears. Enter a 4-digit password using the number buttons, then press ENTER. The display for confirming the password appears. N When you have already registered a password The display for entering the password appears. 4 Enter or re-enter your 4-digit password using the number buttons, then press ENTER. The display for setting the playback limitation level appears. 5 Press X/x to select “STANDARD,” then press ENTER. The selection items for “STANDARD” are displayed. 6 Press X/x to select a geographic area as the playback limitation level, then press ENTER. The area is selected. When you select “OTHERS t,” select and enter a standard code in the table on page 58. 7 Press X/x to select “LEVEL,” then press ENTER. The selection items for “LEVEL” are displayed. 8 Select the level you want using X/x, then press ENTER. Parental Control setting is complete. The lower the value, the stricter the limitation. To turn off the Parental Control function Set “LEVEL” to “OFF” in Step 8. PARENTAL CONTROL Enter a new 4-digit password, then press . ENTER PARENTAL CONTROL Enter password, then press . ENTER PARENTAL CONTROL LEVEL: OFF USA STANDARD: PARENTAL CONTROL LEVEL: OFF USA STANDARD: USA OTHERS PARENTAL CONTROL LEVEL: OFF OFF STANDARD: 8: 7: 6: 5: NC17 R PARENTAL CONTROL LEVEL: STANDARD: USA 4: PG13 c continued www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 1-15 61 Settings and Adjustments Settings and Adjustments Using the Setup Display By using the Setup Display, you can make various adjustments to items such as picture and sound. You can also set a language for the subtitles and the Setup Display, among other things. The on-screen displays differ depending on the player model. For details on each Setup Display item, see pages from 62 to 67. Note Playback settings stored in the disc take priority over the Setup Display settings and not all the functions described may work. 1 Press DISPLAY when the player is in stop mode. The Control Bar appears. 2 Press X/x to select (SETUP), then press ENTER. 3 Press X/x to select “CUSTOM,” then press ENTER. The Setup Display appears. 4 Press X/x to select the setup item from the displayed list: “LANGUAGE SETUP,” “SCREEN SETUP,” “CUSTOM SETUP,” or “AUDIO SETUP.” Then press ENTER. The Setup item is selected. Example: “SCREEN SETUP” 5 Select an item using X/x, then press ENTER. The options for the selected item appear. Example: “TV TYPE” QUICK LANGUAGE SETUP MENU: AUDIO: SUBTITLE: ORIGINAL ENGLISH OSD: ENGLISH ENGLISH SCREEN SETUP TV TYPE: SCREEN SAVER: BACKGROUND: 4:3 LETTER BOX ON JACKET PICTURE Selected item Setup items SCREEN SETUP TV TYPE: SCREEN SAVER: BACKGROUND: 4:3 LETTER BOX 4:3 LETTER BOX 4:3 PAN SCAN 16:9 Options c continued 62 6 Select a setting using X/x, then press ENTER. The setting is selected and setup is complete. Example: “16:9” To turn off the display Press DISPLAY repeatedly until the display is turned off. To enter the Quick Setup mode Select “QUICK” in Step 3. Follow from Step 5 of the Quick Setup explanation to make basic adjustments (page 25). To reset all of the “SETUP” settings If you select “RESET” in Step 3, you can reset all of the “SETUP” settings on pages 62 to 67 to the default settings. After you select “RESET” and press ENTER, select “YES” and press ENTER to reset the settings (it takes a few seconds to complete), or select “NO” and press ENTER to return to the Control Bar. Do not press [/1 when resetting the player. Setting the Display or Sound Track Language (LANGUAGE SETUP) “LANGUAGE SETUP” allows you to set various languages for the on-screen display or sound track. Select “LANGUAGE SETUP” in the Setup Display. To use the display, see “Using the Setup Display” (page 61). NOSD (On-Screen Display) Switches the display language on the screen. NMENU (DVD only) You can select the desired language for the disc’s menu. NAUDIO (DVD only) Switches the language of the sound track. When you select “ORIGINAL,” the language given priority in the disc is selected. NSUBTITLE (DVD only) Switches the language of the subtitle recorded on the DVD. When you select “AUDIO FOLLOW,” the language for the subtitles changes according to the language you selected for the sound track. z Hint If you select “OTHERS t” in “MENU,” “SUBTITLE,” and “AUDIO,” select and enter a language code from “Language Code List” on page 74 using the number buttons. Note When you select a language in “MENU,” “SUBTITLE,” or “AUDIO” that is not recorded on the DVD, one of the recorded languages will be automatically selected. SCREEN SETUP TV TYPE: SCREEN SAVER: BACKGROUND: 16:9 ON JACKET PICTURE Selected setting LANGUAGE SETUP OSD: MENU: AUDIO: SUBTITLE: ENGLISH ENGLISH ORIGINAL ENGLISH 63 Settings and Adjustments Settings for the Display (SCREEN SETUP) Choose settings according to the TV to be connected. Select “SCREEN SETUP” in the Setup Display. To use the display, see “Using the Setup Display” on page 61. The default settings are underlined. The on-screen displays differ depending on the player model. N TV TYPE Selects the aspect ratio of the connected TV (4:3 standard or wide). Note Depending on the DVD, “4:3 LETTER BOX” may be selected automatically instead of “4:3 PAN SCAN” or vice versa. N COLOR SYSTEM (VIDEO CD only; For Asian/Oceanian models only) Selects the color system when you play a VIDEO CD. Notes • You cannot change the color system for DVDs. • You can change the color system of this player according to the connected TV. See page 16. N SCREEN SAVER The screen saver image appears when you leave the player in pause or stop mode for 15 minutes, or when you play back a CD or DATA CD (MP3 audio) for more than 15 minutes. The screen saver will help prevent your display device from becoming damaged (ghosting). Press H to turn off the screen saver. 4:3 LETTER BOX Select this when you connect a 4:3 screen TV. Displays a wide picture with bands on the upper and lower portions of the screen. 4:3 PAN SCAN Select this when you connect a 4:3 screen TV. Automatically displays the wide picture on the entire screen and cuts off the portions that do not fit. 16:9 Select this when you connect a wide-screen TV or a TV with a wide mode function. SCREEN SETUP TV TYPE: SCREEN SAVER: BACKGROUND: 16:9 ON JACKET PICTURE COLOR SYSTEM: AUTO Example: Asian/Oceanian models AUTO Outputs the video signal in the system of the VIDEO CD, either PAL or NTSC. If your TV is the DUAL system, select AUTO. PAL Changes the video signal of an NTSC VIDEO CD and outputs it in the PAL system. NTSC Changes the video signal of a PAL VIDEO CD and outputs it in the NTSC system. ON Turns on the screen saver. 4:3 PAN SCAN 4:3 LETTER BOX 16:9 c continued 64 N BACKGROUND Selects the background color or picture on the TV screen in stop mode or while playing a CD or DATA CD (MP3 audio). Custom Settings (CUSTOM SETUP) Use this to set up playback related and other settings. Select “CUSTOM SETUP” in the Setup Display. To use the display, see “Using the Setup Display” (page 61). The default settings are underlined. NAUTO POWER OFF (For U.S./Canadian models only) Switches the Auto Power Off setting on or off. For Asian/Oceanian models, the Auto Power Off function is fixed to on. NAUTO PLAY Switches the Auto Play setting on or off. This function is useful when the player is connected to a timer (not supplied). NDIMMER Adjusts the lighting of the front panel display. OFF Turns off the screen saver. JACKET PICTURE The jacket picture (still picture) appears, but only when the jacket picture is already recorded on the disc (CD- EXTRA, etc.). If the disc does not contain a jacket picture, the “GRAPHICS” picture appears. GRAPHICS A preset picture stored in the player appears. BLUE The background color is blue. BLACK The background color is black. OFF Switches this function off. ON The player enters standby mode when left in stop mode for more than 30 minutes. OFF Switches this function off. ON Automatically starts playback when the player is turned on. BRIGHT Makes the lighting bright. DARK Makes the lighting dark. OFF Turns off the lighting. CUSTOM SETUP AUTO POWER OFF: AUTO PLAY: DIMMER: OFF OFF BRIGHT AUTO PAUSE MODE: OFF TRACK SELECTION: ON MULTI-DISC RESUME: www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 1-16 66 N DOWNMIX (DVD only) Switches the method for mixing down to 2 channels when you play a DVD which has rear sound elements (channels) or is recorded in Dolby Digital format. For details on the rear signal components, see “Checking the audio signal format” (page 47). This function affects the output of the following jacks: – LINE OUT L/R (AUDIO) jacks – DIGITAL OUT (COAXIAL) jack when “DOLBY DIGITAL” is set to “D-PCM” (page 66). N DIGITAL OUT Selects if audio signals are output via the DIGITAL OUT (COAXIAL) jack. Setting the digital output signal Switches the method of outputting audio signals when you connect a component such as an amplifier (receiver) or MD deck with a digital input jack. For connection details, see page 20. Select “DOLBY DIGITAL,” “MPEG” and “DTS” after setting “DIGITAL OUT” to “ON.” If you connect a component that does not conform to the selected audio signal, a loud noise (or no sound) will come out from the speakers, affecting your ears or causing the speakers to be damaged. NDOLBY DIGITAL (DVD only) Selects the type of Dolby Digital signal. DOLBY SUR- ROUND Select this when the player is connected to an audio component that conforms to Dolby Surround (Pro Logic). NORMAL Select this when the player is connected to an audio component that does not conform to Dolby Surround (Pro Logic). ON Normally select this position. When you select “ON,” see “Setting the digital output signal” for further settings. OFF The influence of the digital circuit upon the analog circuit is minimal. D-PCM Select this when the player is connected to an audio component lacking a built-in Dolby Digital decoder. You can select whether the signals conform to Dolby Surround (Pro Logic) or not by making adjustments to the “DOWNMIX” item in “AUDIO SETUP” (page 66). DOLBY DIGITAL Select this when the player is connected to an audio component with a built-in Dolby Digital decoder. AUDIO SETUP AUDIO ATT: AUDIO DRC: DOLBY DIGITAL: MPEG: OFF STANDARD DOWNMIX: DOLBY SURROUND D-PCM PCM DTS: OFF DIGITAL OUT: ON Example: Asian/Oceanian models 67 Settings and Adjustments N MPEG (DVD only; For Asian/Oceanian models only) Selects the type of MPEG audio signal. N DTS (DVD only) Selects whether or not to output DTS signal. Note If you select one of the TVS settings while playing a DVD, the player does not output the following signals from the DIGITAL OUT (COAXIAL) jack. – Dolby Digital signals (when you set “DOLBY DIGITAL” in “AUDIO SETUP” to “D-PCM”) (page 66) – MPEG audio signals PCM Select this when the player is connected to an audio component lacking a built-in MPEG decoder. If you play MPEG audio sound tracks, the player outputs stereo signals via the DIGITAL OUT (COAXIAL) jack. MPEG Select this when the player is connected to an audio component with a built-in MPEG decoder. OFF Select this when the player is connected to an audio component lacking a built-in DTS decoder. ON Select this when the player is connected to an audio component with a built-in DTS decoder. 65 Settings and Adjustments N PAUSE MODE (DVD only) Selects the picture in pause mode. N TRACK SELECTION (DVD only) Gives the sound track which contains the highest number of channels priority when you play a DVD on which multiple audio formats (PCM, DTS, MPEG audio or Dolby Digital format) are recorded. Notes • When you set the item to “AUTO,” the language may change. The “TRACK SELECTION” setting has higher priority than the “AUDIO” settings in “LANGUAGE SETUP” (page 62). • If you set “DTS” to “OFF” (page 67), the DTS sound track is not played even if you set “TRACK SELECTION” to “AUTO.” • If PCM, DTS, MPEG audio and Dolby Digital sound tracks have the same number of channels, the player selects PCM, DTS, Dolby Digital, and MPEG audio sound tracks in this order. N MULTI-DISC RESUME (DVD/VIDEO CD only) Switches the Multi-disc Resume setting on or off. Resume playback can be stored in memory for up to 6 different DVD/VIDEO CD discs (page 32). Settings for the Sound (AUDIO SETUP) “AUDIO SETUP” allows you to set the sound according to the playback and connection conditions. Select “AUDIO SETUP” in the Setup Display. To use the display, see “Using the Setup Display” (page 61). The default settings are underlined. The on-screen displays differ depending on the player model. N AUDIO ATT (attenuation) If the playback sound is distorted, set this item to “ON.” The player reduces the audio output level. This function affects the output of the LINE OUT L/R (AUDIO) jacks. N AUDIO DRC (Dynamic Range Control) (DVD only) Makes the sound clear when the volume is turned down when playing a DVD that conforms to “AUDIO DRC.” This affects the output from the following jacks: – LINE OUT L/R (AUDIO) jacks – DIGITAL OUT (COAXIAL) jack only when “DOLBY DIGITAL” is set to “D- PCM” (page 66). AUTO The picture, including subjects that move dynamically, is output with no jitter. Normally select this position. FRAME The picture, including subjects that do not move dynamically, is output in high resolution. OFF No priority given. AUTO Priority given. ON Stores the resume settings in memory for up to 6 discs (The settings remain in memory even if you select “OFF.”) OFF Does not store the resume settings in memory. Playback restarts at the resume point only for the current disc in the player. OFF Normally, select this position. ON Select this when the playback sound from the speakers is distorted. STANDARD Normally select this position. TV MODE Makes the low sounds clear even if you turn the volume down. WIDE RANGE Gives you the feeling of being at a live performance. AUDIO SETUP AUDIO ATT: AUDIO DRC: DIGITAL OUT: OFF STANDARD ON DOWNMIX: DOLBY SURROUND DOLBY DIGITAL: DTS: D-PCM OFF c continued 68 Additional Information Troubleshooting If you experience any of the following difficulties while using the player, use this troubleshooting guide to help remedy the problem before requesting repairs. Should any problem persist, consult your nearest Sony dealer. Power The power is not turned on. , Check that the AC power cord is connected securely. Picture There is no picture/picture noise appears. , Re-connect the connecting cord securely. , The connecting cord is damaged. , Check the connection to your TV (page 18) and switch the input selector on your TV so that the signal from the player appears on the TV screen. , The disc is dirty or flawed. , If the picture output from your player goes through your VCR to get to your TV or if you are connected to a combination TV/ VIDEO player, the copy-protection signal applied to some DVD programs could affect picture quality. If you still experience problems even when you connect your player directly to your TV, please try connecting your player to your TV’s S VIDEO input (page 18). , If the color system of your player does not match with that of your TV, change the color system of the player. For details, see page 16. (You cannot change the color system of the DVD disc itself.) Even though you set the aspect ratio in “TV TYPE” of “SCREEN SETUP,” the picture does not fill the screen. , The aspect ratio of the disc is fixed on your DVD. The picture is black and white. , Depending on the TV, the picture on the screen becomes black and white when you play a disc recorded in the NTSC color system. Sound There is no sound. , Re-connect the connecting cord securely. , The connecting cord is damaged. , The player is connected to the wrong input jack on the amplifier (receiver) (page 22, 23, 24). , The amplifier (receiver) input is not correctly set. , The player is in pause mode or in Slow- motion Play mode. , The player is in fast forward or fast reverse mode. , If the audio signal does not come through the DIGITAL OUT (COAXIAL) jack, check the audio settings (page 66). , While playing a Super VCD on which the audio track 2 is not recorded, no sound will come out when you select “2:STEREO,” “2:1/L” or “2:2/R.” Sound is noisy. , When playing a CD with DTS sound tracks, noise will come from the LINE OUT L/R (AUDIO) jacks or DIGITAL OUT (COAXIAL) jack (page 28). Sound distortion occurs. , Set “AUDIO ATT” in “AUDIO SETUP” to “ON” (page 65). The sound volume is low. , The sound volume is low on some DVDs. The sound volume may improve if you set “AUDIO DRC” to “TV MODE” (page 65) and set “DOWNMIX” to “NORMAL” (page 66). , Set “AUDIO ATT” in “AUDIO SETUP” to “OFF” (page 65). Operation The remote does not function. , There are obstacles between the remote and the player. , The distance between the remote and the player is too far. , The remote is not pointed at the remote sensor on the player. , The batteries in the remote are weak. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 1-17 69 Additional Information The disc does not play. , The disc is turned over. Insert the disc with the playback side facing down on the disc tray. , The disc is skewed. , The player cannot play certain discs (page 7). , The region code on the DVD does not match the player. , Moisture has condensed inside the player (page 3). , The player cannot play CD-Rs, CD-RWs, DVD-Rs, or DVD-RWs (video mode) that are not finalized (page 7). The following message appears when you play a DATA CD. “Data error” , The MP3 audio track you want to play is broken. , The data is not MPEG1 Audio Layer 3 data. The MP3 audio track cannot be played (page 35). , The DATA CD is not recorded in the MP3 format that conforms to ISO9660 Level 1/ Level 2 or Joliet. , The MP3 audio track does not have the extension “.MP3.” , The data is not formatted in MP3 even though it has the extension “.MP3.” , The data is not MPEG1 Audio Layer 3 data. , The player cannot play audio tracks in MP3PRO format. The title of the MP3 audio album or track is not correctly displayed. , The player can only display numbers and alphabet. Other characters are displayed as asterisks. The disc does not start playing from the beginning. , Program Play, Shuffle Play, Repeat Play, or A-B Repeat Play has been selected (page 37). , Resume play has taken effect (page 32). The player starts playing the disc automatically. , The disc features an auto playback function. , “AUTO PLAY” in “CUSTOM SETUP” is set to “ON” (page 64). Playback stops automatically. , While playing discs with an auto pause signal, the player stops playback at the auto pause signal. You cannot perform some functions such as Stop, Search, Slow-motion Play, Repeat Play, Shuffle Play, or Program Play. , Depending on the disc, you may not be able to do some of the operations above. See the operating manual that comes with the disc. The language for the sound track cannot be changed. , Try using the DVD’s menu instead of the direct selection button on the remote (page 33). , Multilingual tracks are not recorded on the DVD being played. , The DVD prohibits the changing of the language for the sound track. The subtitle language cannot be changed or turned off. , Try using the DVD’s menu instead of the direct selection button on the remote (page 33). , Multilingual subtitles are not recorded on the DVD being played. , The DVD prohibits the changing of the subtitles. The angles cannot be changed. , Try using the DVD’s menu instead of the direct selection button on the remote (page 33). , Multi-angles are not recorded on the DVD being played. , The angle can only be changed when the “ANGLE” indicator lights up on the front panel display (page 10). , The DVD prohibits changing of the angles. The player does not operate properly. , When static electricity, etc., causes the player to operate abnormally, unplug the player. Nothing is displayed on the front panel display. , “DIMMER” in “CUSTOM SETUP” is set c continued 70 to “OFF.” Set “DIMMER” to “BRIGHT” or “DARK” (page 64). 5 numbers or letters are displayed on the screen and on the front panel display. , The self-diagnosis function was activated. (See the table on page 70.) The disc tray does not open and “LOCKED” appears on the front panel display. , Child Lock is set (page 30). The disc tray does not open and “TRAY LOCKED” appears on the front panel display. , Contact your Sony dealer or local authorized Sony service facility. Self-diagnosis Function (When letters/numbers appear in the display) When the self-diagnosis function is activated to prevent the player from malfunctioning, a five-character service number (e.g., C 13 50) with a combination of a letter and four digits appears on the screen and the front panel display. In this case, check the following table. First three characters of the service number Cause and/or corrective action C 13 The disc is dirty. ,Clean the disc with a soft cloth (page 8). C 31 The disc is not inserted correctly. ,Re-insert the disc correctly. E XX (xx is a number) To prevent a malfunction, the player has performed the self-diagnosis function. ,Contact your nearest Sony dealer or local authorized Sony service facility and give the 5- character service number. Example: E 61 10 71 Additional Information Glossary Chapter (page 10) Sections of a picture or a music feature that are smaller than titles. A title is composed of several chapters. Depending on the disc, no chapters may be recorded. Dolby Digital (page 24, 66) Digital audio compression technology developed by Dolby Laboratories. This technology conforms to 5.1-channel surround sound. The rear channel is stereo and there is a discrete subwoofer channel in this format. Dolby Digital provides the same 5.1 discrete channels of high quality digital audio found in Dolby Digital cinema audio systems. Good channel separation is realized because all of the channel data are recorded discretely and little deterioration is realized because all channel data processing is digital. Dolby Surround (Pro Logic) (page 23) Audio signal processing technology that Dolby Laboratories developed for surround sound. When the input signal contains a surround component, the Pro Logic process outputs the front, center and rear signals. The rear channel is monaural. DTS (page 24, 67) Digital audio compression technology that Digital Theater Systems, Inc. developed. This technology conforms to 5.1-channel surround sound. The rear channel is stereo and there is a discrete subwoofer channel in this format. DTS provides the same 5.1 discrete channels of high quality digital audio. Good channel separation is realized because all of the channel data is recorded discretely and little deterioration is realized because all channel data processing is digital. DVD (page 7) A disc that contains up to 8 hours of moving pictures even though its diameter is the same as a CD. The data capacity of a single-layer and single- sided DVD is 4.7 GB (Giga Byte), which is 7 times that of a CD. The data capacity of a double-layer and single-sided DVD is 8.5 GB, a single-layer and double-sided DVD is 9.4 GB, and double-layer and double-sided DVD is 17GB. The picture data uses the MPEG 2 format, one of the worldwide standards of digital compression technology. The picture data is compressed to about 1/40 (average) of its original size. The DVD also uses a variable rate coding technology that changes the data to be allocated according to the status of the picture. Audio information is recorded in a multi-channel format, such as Dolby Digital, allowing you to enjoy a more real audio presence. Furthermore, various advanced functions such as the multi-angle, multilingual, and Parental Control functions are provided with the DVD. Index (CD)/Video Index (VIDEO CD) (page 10) A number that divides a track into sections to easily locate the point you want on a CD or VIDEO CD. Depending on the disc, no index may be recorded. MPEG audio (page 24, 67) International standard coding system used to compress audio digital signals authorized by ISO/IEC. MPEG 1 conforms to up to 2- channel stereo. MPEG 2, used on DVDs, conforms to up to 7.1-channel surround. Scene (page 10) On a VIDEO CD with PBC (playback control) functions, the menu screens, moving pictures and still pictures are divided into sections called “scenes.” c continued 72 Title (page 10) The longest section of a picture or music feature on a DVD, movie, etc., in video software, or the entire album in audio software. Track (page 10) Sections of a picture or a music feature on a CD or VIDEO CD (the length of a song). www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 1-18E 74 Language Code List For details, see pages 46, 50, 62. The language spellings conform to the ISO 639: 1988 (E/F) standard. Code Language Code Language Code Language Code Language 1027 Afar 1028 Abkhazian 1032 Afrikaans 1039 Amharic 1044 Arabic 1045 Assamese 1051 Aymara 1052 Azerbaijani 1053 Bashkir 1057 Byelorussian 1059 Bulgarian 1060 Bihari 1061 Bislama 1066 Bengali; Bangla 1067 Tibetan 1070 Breton 1079 Catalan 1093 Corsican 1097 Czech 1103 Welsh 1105 Danish 1109 German 1130 Bhutani 1142 Greek 1144 English 1145 Esperanto 1149 Spanish 1150 Estonian 1151 Basque 1157 Persian 1165 Finnish 1166 Fiji 1171 Faroese 1174 French 1181 Frisian 1183 Irish 1186 Scots Gaelic 1194 Galician 1196 Guarani 1203 Gujarati 1209 Hausa 1217 Hindi 1226 Croatian 1229 Hungarian 1233 Armenian 1235 Interlingua 1239 Interlingue 1245 Inupiak 1248 Indonesian 1253 Icelandic 1254 Italian 1257 Hebrew 1261 Japanese 1269 Yiddish 1283 Javanese 1287 Georgian 1297 Kazakh 1298 Greenlandic 1299 Cambodian 1300 Kannada 1301 Korean 1305 Kashmiri 1307 Kurdish 1311 Kirghiz 1313 Latin 1326 Lingala 1327 Laothian 1332 Lithuanian 1334 Latvian; Lettish 1345 Malagasy 1347 Maori 1349 Macedonian 1350 Malayalam 1352 Mongolian 1353 Moldavian 1356 Marathi 1357 Malay 1358 Maltese 1363 Burmese 1365 Nauru 1369 Nepali 1376 Dutch 1379 Norwegian 1393 Occitan 1403 (Afan)Oromo 1408 Oriya 1417 Punjabi 1428 Polish 1435 Pashto; Pushto 1436 Portuguese 1463 Quechua 1481 Rhaeto- Romance 1482 Kirundi 1483 Romanian 1489 Russian 1491 Kinyarwanda 1495 Sanskrit 1498 Sindhi 1501 Sangho 1502 Serbo- Croatian 1503 Singhalese 1505 Slovak 1506 Slovenian 1507 Samoan 1508 Shona 1509 Somali 1511 Albanian 1512 Serbian 1513 Siswati 1514 Sesotho 1515 Sundanese 1516 Swedish 1517 Swahili 1521 Tamil 1525 Telugu 1527 Tajik 1528 Thai 1529 Tigrinya 1531 Turkmen 1532 Tagalog 1534 Setswana 1535 Tonga 1538 Turkish 1539 Tsonga 1540 Tatar 1543 Twi 1557 Ukrainian 1564 Urdu 1572 Uzbek 1581 Vietnamese 1587 Volapük 1613 Wolof 1632 Xhosa 1665 Yoruba 1684 Chinese 1697 Zulu 1703 Not specified www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 2-1 SECTION 2 DISASSEMBLY DVP-NC615/NC655P 2-1. DISASSEMBLY 2-2. UPPER CASE 4 Upper case 1 Two tapping screws 2 Two tapping screws 3 Three screws (B3) NOTE: Follow the disassembly procedure in the numerical order given. IF-091, FR-187 boards (Page 2-6) Loading motor ass’y (M901) (Page 2-4) Optical pick-up (Page 2-5) Table ass’y (Page 2-4) AV-062 board (Page 2-3) ER-14 board (AEP, UK) (Page 2-3) Front panel section (Page 2-1) Rear panel section (Page 2-2) MB-103 board (Page 2-2) CN-158 board (Page 2-3) Power block (Page 2-5) Upper case (Page 2-1) Set • This set can be disassembled in the order shown below. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 2-2 2-3. FRONT PANEL SECTION 2-4. REAR PANEL 9 Rear panel 2 Connector (CN202) 1 Flexible flat cable (FMV-20: CN201) 3 Connector (CN101) 4 Re-use clamp 5 Two screws (B3) 6 Screw (B3) 7 Screw (B3) 8 Screw (B3) 1 Flexible flat cable (FCI-1: CN303) 4 Claw 5 Claw 3 Two screws (B3) 2 Two screws (B3) 6 Front panel section www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 2-3 2-5. MB-103 BOARD 6 Connector (CN102) 4 Board to board connector (CN101) 0 MB-103 board 2 Pull the tray in the direction of the arrow B. 1 Insert a flat-head (-) screwdriver into a hole at the bottom, and rotate the cam gear in the direction of the arrow A. A B 9 Four screws (B3) 7 Flexible flat cable (FMO-6: CN204) 8 Flexible flat cable (FMM-42: CN203) 3 Flexible flat cable (FMC-15: CN201) 5 Flexible flat cable (FMV-20: CN601) A B 6 Flexible flat cable (FMC-15: CN301) 4 Connector (CN305) 8 Connector (CN310) 9 Connector (CN309) 5 Connector (CN311) 7 Board to board connector (CN101) qs CN-158 board 1 Insert a flat-head (-) screwdriver into a hole at the bottom, and rotate the cam gear in the direction of the arrow A. 0 Two screws (B3) qa Two screws (B3) 2 Pull the tray in the direction of the arrow B. 3 Flexible flat cable (FCI-1: CN303) 2-6. CN-158 BOARD www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 2-4 2-8. ER-14 BOARD (AEP, UK) 2-9. TABLE ASS’Y 6 Harness 1 Connector (CN001) 7 Table assembly 4 Two screws (B3) 5 Two screws (B3) 2 Flexible flat cable (FMO-6: CN204) 3 Flexible flat cable (FMM-42: CN203) 2-7. AV-062 BOARD 3 AV-062 board 2 Six screws (B3)(NC655P) Five screws (B3)(NC615) 1 Flexible flat cable (FAE-10: CN101) (AEP, UK) 3 ER-14 board 2 Two screws (B3) 1 Flexible flat cable (FAE-10: CN901) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 2-5 2-10.LOADING MOTOR ASS’Y 2-11.OPTICAL PICK-UP 3 MD-94 board 6 Belt (timing) 4 Connector (CN004) 9 Loading motor assembly (M901) 2 Claw 5 Claws 7 Screw (M2.6 × 4) 8 Screw (M2.6 × 4) 1 Screw (M2.6 × 8) 3 Flexible flat cable (FMM-42, 26P) 6 Optical pick-up 5 Three step screws 4 Flexible flat cable (FMO-6, 9P) 1 Two screws (B3) 2 Chuck assy www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 2-6 2-12.POWER BLOCK 7 Connector (CN407) 0 FR-187 board 9 IF-091 board 6 Front panel 1 Flat clamp Hole 8 Board to board connector (CN403, CN701) 5 Front bracket 2 Four screws (M2.6 × 8) 3 Nine screws (M2.6 × 8) Flexible flat cable (FCI-1) 4 Flexible flat cable (FCI-1) 2-13.IF-091 AND FR-187 BOARDS 2 Connector (CN101) 7 Power block 6 Holder, PS 5 Two claws 1 Connector (CN201) 3 Harness 4 Two screws (B3) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 2-7 2-14.INTERNAL VIEWS Optical pick-up (KHM-270AAA/Service assembly) A-6062-709-A TD unit ass'y A-6060-640-A PH102 (on the SE-130 board) PH101 (on the SE-130 board) M901 Loading motor ass'y X-3952-378-1 Encoder ass'y (loading) X-3952-380-1 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 2-8E 2-15.CIRCUIT BOARDS LOCATION IF-091 board (IF COM) PL-031 board (LED) FR-187 board (FUNCTION SW/LED) MD-94 board (MD INTERFACE) CN-158 board (CONNECTOR) MB-103 board DVD/CD RF AMP, DIGITAL SERVO, MOTOR DRIVE, AV DECODER, SDRAM, SYSTEM CONTROL, AUDIO DAC, PLL, I/P CONVERTER, VIDEO ENCODER AV-062 board (AUDIO/VIDEO OUT) ER-14 board (LINE1 OUT) SE-130 board (SENSOR) POWER BLOCK (SWITCHING REGULATOR) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DVP-NC615/NC655P SECTION 3 BLOCK DIAGRAMS 3-1. OVERALL BLOCK DIAGRAM 3-1 3-2 IC201 IC301 IC403 IC303 IC101 IC601 IC901 IC401 IC404,405 * IC504 IC102 J101 (1/2) J101 (2/2) J103 J102 IC202 BASE UNIT KHM-270AAA/SERVICE ASSY MB-103 BOARD (SEE PAGE 4-11 to 4-26) AV-62 BOARD (SEE PAGE 4-31 to 4-34) ER-14 BOARD (SEE PAGE 4-37) OPTICAL DEVICE DVD/CD PD IC RF DVD/CD RF AMP, SERVO ERROR PROCESS SIG 0 ARP, SERVO DSP FOCUS COIL TRACKING COIL FOCUS/ TRACKING COIL DRIVE, SPINDLE/ SLED/ LOADING MOTOR DRIVE M M M SPINDLE MOTOR SLED MOTOR LOADING MOTOR FUNCTION KEY ND401 VACUUM FLUORESCENT DISPLAYS IF CON P-CONT SW-13V EVER+3.3V +11V SERIAL BUS ITC BUS EEPROM PARALLEL BUS CDDOUT, CDDATA, CDBCK, CDLRCK SDI 0 – 7 AV DECODER SPDIF, ACH12, ACH34, ACH56, BCK, LRCK 16M DRAM 16M SDRAM VIDEO ENCODER Y, Cb, Cr V, Y, C VIDEO BUFFER VIDEO BUFFER, SELECT SWITCH SPDIF IC204 AUDIO D/A CONVERTER IC201 AUDIO AMP INLIMIT SENSOR ROTARY ENCODER CN-158 BOARD (SEE PAGE 4-49) SE-130 BOARD (SEE PAGE 4-53) M TURNTABLE MOTOR FUNCTION KEY FUNCTION LED PROG LED +3.3V +11V AU+5V +1.8V –5V HS10S1U BOARD : US, Canadian (SEE PAGE 4-57) HS10S1F BOARD : AEP, UK, Australian, PX, E, Singapore (SEE PAGE 4-57) SWITCHING REG AC IN 16 EXCEPT AEP,UK AEP,UK NC655P NC615 V, Y, C R, G, B LINE1 (RGB) –TV CNJ902 PB COMPONENT VIDEO OUT Y PR NC615 LINE OUT VIDEO 1 VIDEO 2 VIDEO S VIDEO OUT L R LINE OUT AUDIO 2 L R AUDIO 1 L R AUDIO 1 OPTICAL DIGITAL OUT COAXIAL J201 D11 – 14 F1 REG AU+5V REG REG IC104 SYSTEM CONTROL IC108 IM SRAM PUSH ENTER CURSOR STICK *IC405 : AEP,UK IC106 FLASH or IC107 OTP PH501, 502 SENSOR IC303 TURNTABLE MOTOR DRIVE IC702 D/A CONVERTER IC406 REMOTE COMMANDER RECEIVER FR-187 BOARD (SEE PAGE 4-45) PL-031 BOARD (SEE PAGE 4-41) IF-91 BOARD (SEE PAGE 4-41) +5V +11V EVER+3.3V SW–13V NC655P NC655P MD-94 BOARD NC655P BUZZER SW+3.3V IC502 I/P CONVERTOR IC503 16M SDRAM Y, Cb, Cr V, Y, C NC655P NC615 NC655P NC655P NC655P NC655P w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DVP-NC615/NC655P 3-3 3-4 3-2. RF/SERVO BLOCK DIAGRAM 2 19 25 27 59 42 41 36 38 44 13 15 21 33 37 14 ı 11 7 ı 10 45 ı 48 32 ı 29 125 124 126 147 131 148 152 15 ı 18 37 36 21 22 48 1 47 46 20 22 15 17 35 34 27 28 7 10 25 24 3 4 45 5 128 153 154 146 12 11 143 144 32 33 MB-103 BOARD (1/4) (SEE PAGE 4-11, 13, 19) BASE UNIT KHM-240AAA/J1RP OPTICAL DEVICE 24 25 17 16 22 20 13 8 12 4 3 15 23 18 26 2 1 Q201 DVD LD DRIVE IC201 IC301 DVD/CD PD IC DVD/CD LD MODULE CN203 DVD/CD RF AMP, SERVO ERROR PROCESS RF IN A – D E – H A2 – D2 VC DVDPD CDPD DVDLD SIGO FE TE PI DFT MON MIRR TZC SRD SWD SCLK SDEN SERVO DSP ADC1 ADC0 ADC2 DFCTI ADC7 POM 2, 3 129 130 ADC5, 6 MIRR TZC ADC4 SIGNAL PROCESSOR (SEE PAGE 3-5) SYSTEM CONTROL (SEE PAGE 3-7) XRESET HCS HINT MDSO MDPO 163 164 GIO9/FGREF GIO10/FGIN GIO1/INT3 PWM2 PWM0, 1 POM 0, 1 GIO0/INT2 SPINDLE MOTOR DRIVE FOCUS COIL DRIVE TRACKING COIL DRIVE SLED MOTOR DRIVE LOADING MOTOR DRIVE 7 1 ı 4 9 8 8 5 4 IC202 IC303 TURNTABLE MOTOR DRIVE 10 CN201 LDM LM INLIMIT SENSOR TRACKING COIL FOCUS COIL LOADING MOTOR M M M SLED MOTOR SPINDLE MOTOR CN204 1 2 CKSW1 OCSW1 7 OCSW2 TM TURNTABLE MOTOR M SE-130 BOARD 39 VCI 19 39 20 22 16 17 155 GIO2/INT4 16 (1/2) RF A – D E – H VC PD 24 10 LEDSEL0 SW DVD LD 26 6 Q202 CD LD DRIVE CDLD CD LD VR SLA , SLB SPM INLIM TRK ADC3 FCS PS TSD-M 40 42 43 VREF +3.3V LDON 159 162 167 GIO6/SDI GIO7/SDO GIO8/SCK GIO13 XSDPIT XSDPCS XRST XDRVMUTE CMDREQ/TSENSD/CLPBSY X39IT/TSENSU/OTASUKE SIG 0 DSENS TRM–/XKRCS TRM+/XKRRST OCSW2 OCSW1 CKSW1 XLDON FE TE PI SSDFCTI SS MON MDSO, MDPO SPMUTE SLDA, SLDB LMP, LMM TSD LMCTL TDRV FDRV SPFG SLE ROTARY ENCODER LM 1 2 1 2 DISC SENSOR PH101 5 4 TM DSENS TSENS CN301 CN305 CN-158 BOARD (1/2) (SEE PAGE 4-49) 10 11 8 9 4 2 9 3 TMP 11 1 TMM DSENS TSENS 2 3 1 7 8 11 10 5 6 7 2 4 9 7 OUT1, 2 FIN RIN IC302 (DVD play) 100 mV/DIV 50 ms/DIV 160 mVp-p IC302 (CD play) 500 mV/DIV 50 ms/DIV 860 mVp-p IC302 (DVD play) 500 mV/DIV 50 ms/DIV 1.4 Vp-p IC302 (CD play) 500 mV/DIV 200 mV/DIV 1.7 Vp-p 570 mVp-p IC202 (DVD play) 200 mV/DIV 50 ns/DIV IC202 (CD play) 200 mV/DIV 200 ns/DIV 550 mVp-p IC202 (DVD play) 500 mV/DIV 50 ms/DIV 1.5 Vp-p 1.7 Vp-p IC202 (CD play) 500 mV/DIV 200 ms/DIV 180 mVp-p IC202 (DVD play) 100 mV/DIV 50 ms/DIV 860 mVp-p IC202 (CD play) 500 mV/DIV 50 ms/DIV 1.4 Vp-p IC202 (DVD play) 500 mV/DIV 50 ns/DIV 1.4 Vp-p IC202 (CD play) 500 mV/DIV 200 ns/DIV 10 11 8 9 2 3 1 6 7 MD-94 BOARD 1 2 CN001 CN004 2 3 CN003 S001 5 6 2 3 TRAY SENSOR PH102 DSENS TSENS CN002 TM 161 127 61 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DVP-NC615/NC655P 3-5 3-6 3-3. SIGNAL PROCESSOR BLOCK DIAGRAM SDCK, XSHD, XSRQ, XSAK, SDEF SDCK XSHD XSRQ XSAK SDEF DATA BCLK LRCK DOUT CDIN2I CDIN1I CDBCKI CDLRKI ICLKI IERRI ISTARTI IVALI IREQO 111 113 24 25 26 27 28 150 196 197 207 22 156 70 24 25 63 55 65 61 59 57 26 28 29 166 167 158 160 134 ı 141 2 ı 9 37 ı 40 42 ı 45 169 170 175 56 57 ı 59 63 64 47 ı 51 77 ı 84 65 – 74 MEMA 0 – 9 MEMD 0 – 15 ADAD 0 – 11 ADDT 0 – 15 105-108 110-113 115 116 118 120 135-138 140-143 145-148 150 151 153 154 168-169 171-174 176-179 181-184 186-189 191-194 2 – 5 7 – 10 12 – 15 17 – 20 122 124 125 127 129 130 132 133 36 – 43 46 – 53 29 31 30 IC303 16M DRAM IC301 ARP IC403 AV DECODER 31 32 34 35 202 – 205 MB-103 BOARD (2/4) (SEE PAGE 4-13 to 4-18) SIG 0 RF/SERVO (SEE PAGE 3-4) SYSTEM CONTROL (SEE PAGE 3-7) 16 RFIN1 RFIN2 SD 0 – 7 SDI 0 – 7 DTI 0 – 7 MA 0 – 9 MD 0 – 15 SDDQ 0 – 15 CDDATA, CDBCK, CDLRCK, CDDOUT CLK, CKE, DQML, DQMU, CS, WE, CAS, RAS WE, RAS LCAS, UCAS C OUT Y OUT COMPOUT B OUT R OUT G OUT C Y V Cr/B Cb/R Y/G COUT YOUT COMPOUT CR/B CB/R Y/G VIDEO (SEE PAGE 3-11) AUDIO (SEE PAGE 3-13) VREFI ACH12 ACH34 ACH56 LAND LRCKO BCKO ACH12 LRCK BCK VIDEO LEVEL ADJ RV401 HD 0 – 15 HAD 0 – 21 HA 0 – 21 HD 0 – 15 D 0 – 7 A 0 – 7 HA 0 – 7 HD 8 – 15 XRD XWRH RSTn DM ACK1 DM REQ1 DM ACK0 DM REQ0 ACLK CRPCLKI HAD23 HAD22 CLKI SCLKI 200 199 HWAIT0n HIREQ0 HA 0 – 21 HD 0 – 15 HA 0 – 21 HD 0 – 15 XRST 512FSAVD 33MAVD 33MARP XWRH XRD TRST XARPIT XARPCS XWAIT XAVDCS2 XAVDCS3 27MAVD XAVDIT DREQ0 DACK0 DREQ1 DACK1 XWR XRD XINT XCS XWAT CLKIN 30 DO SPDIF 175 174 173 172 TDO TCK TDI TMS 171 97 99 98 101 102 TRST TDI TCK TDO TMS TRST HCSn HRWn LAND (FOR J TAG) (2/2) 3 CN601 (1/3) 1 11 7 9 5 IC504, 505* 16M SDRAM *IC405: AEP,UK,NC655P IC503 : EXCEPT AEP, UK 620 mVp-p (H) IC503 : AEP, UK (LINE : RGB mode) 660 mVp-p (H) IC503 : EXCEPT AEP, UK 620 mVp-p (H) IC503 : AEP, UK (LINE : RGB mode) 660 mVp-p (H) IC503 940 mVp-p (H) IC503 1.1 Vp-p (H) IC503 : EXCEPT AEP, UK 940 mVp-p (H) IC503 : AEP, UK (LINE : RGB mode) 660 mVp-p (H) IC503 810 mVp-p (H) NC615 ONLY 84 ı 87 89 ı 92 95 D1CLKO DVD 0 - 7 DVD 0 – 7 27MVGA32 27MCLK DVD 0 - 7 VIEDO (SEE PAGE 3-9) NC655P ONLY NC615 ONLY qs IC403 ws 4.8Vp-p 40.8nsec ql IC403 key to go to the next item, or . key to repeat the same check again. Test Mode Menu 0. Syscon Diagnosis 1. Drive Auto Adjustment 2. Drive Manual Operation 3. Mecha Aging 4. Emargency History 5. Version Information 6. Video Level Adjustment Exit: Power Key _ Model : DPX-16xxxx Revision : x.xxx Last Off: xx ### Syscon Diagnosis ### Check Menu 0. Quit 1. All 2. Version 3. Peripheral 4. Servo 5. Supply 6. AV Decoder 7. Video 8. Audio _ ### Syscon Diagnosis ### Diag All Check No. 2 Version 2-3. ROM Check Sum Check Sum = 2005 Press NEXT Key to Continue Press PREV key to Repeat _ www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 6-2 To quit the diagnosis and return to the Check Menu screen, press x or [ENTER] key. If an error occurred, the diagnosis is suspended and the error code is displayed as shown below. Press x key to quit the diagnosis, or . key to repeat the same item where an error occurred, or > key to continue the check from the item next to faulty item. Selecting [2] and subsequent items call the submenu screen of each item. When “———” is displayed in the submenu, it means that the test is not supported in the model. For example, if “5. Supply” is selected, the following submenu will be displayed. 0. (Quit) Quit the submenu and return to the main menu. 1. (All submenu items continuous check.) This menu checks 2 and subsequent items successively. At the item where visual check is required for judgment or an error occurred, the checking is suspended and the message is output for key entry. Normally, all items are checked successively one after another automatically unless an error is found. Selecting [2] and subsequent items executes respective menus and outputs the results. For the contents of each submenu, see “General Description of Checking Method” and “Check Items List”. General Description of Checking Method 2. Version (2-2) Revision ROM revision number is displayed. Error: Not detected. The revision number defined in the source file is displayed with four digits. (2-3) ROM Check Sum Check sum is calculated. Error: Not detected. 8-bit data are added up to the ROM address 0x000F0000 to 0x002EFFFF, and the result is displayed with 4-digit hexa- decimal number. Error is not detected. Compare the result with the specified value. (2-4) Model Type Model code is displayed. Error: Not detected. The model code read from the EEPROM is displayed with 2-digit hexadecimal number. (2-5) Region Region code is displayed. Error: Not detected. The region code determined from the model code is dis- played. (2-6) M’t Check Mount resistance is checked. Error 22: The region code does not accord. Check whether the region code that is deduced from model resistance and destination resistance accords with the re- gion code that is deduced from region resistance value. 3. Peripheral (3-2) EEPROM Check Data write t read, and accord check Error 03: EEPROM write/read discord 0x9249, 0x2942 and 0x4294 are written to the address 0x00 to 0xFF of the EEPROM and then read for checking. Be- fore writing, the data are saved, then after checking, they are written to restore the contents of EEPROM. (3-6) Venc Check (NC655P only) Data write t read, and accord check Error: 52: Write/read data discord Error may occur due to defect of access with syscon. (3-8) External RAM Check (NC655P only) Test Data write t read, and accord check Error: 02: The external RAM used in the system control, is checked. ### Syscon Diagnosis ### 3-2. EEPROM Check Error 03: EEPROM Write/Read N Address : 00000001 Write Data : 2492 Read Data : 2490 Press NEXT Key to Continue Press PREV key to Repeat _ ### Syscon Diagnosis ### Check Menu No. 5 Supply 0. Quit 1. All 2. ARP Register Check 3. ARP to RAM Data Bus 4. ARP to RAM Address Bus 5. ARP RAM Check _ www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 6-3 4. Servo (4-2) Servo DSP Check Data write t read, and accord check Error 12: Read data discord 0x9249, 0x2942 and 0x4294 are written to the RAM ad- dress 0x602 of the Servo DSP and then read for checking. (4-3) ————— Check no support. (4-4) RF Amp Register Check Data write t read, and accord check Error 13: RF Amp register write, and read data discord Implement 8-bit shift operation of the 0x01 to the read- able/writable register of the RF Amp. If once write data do not accord with read data, it is NG. 5. Data Supply System (5-2) ARP Register Check Data write t read, and accord check Error 08: ARP register write, and read data discord Data 0x00 to 0xFF is written sequentially to the ARP TMAX register (address 0xC6) and then read for checking. (5-3) ARP to RAM Data Bus Data write t read, and accord check Error 09: ARP Tt RAM data bus error Data 0x0001 to 0x8000 where one bit each is set to 1 are written to the address 0 of RAM (IC303) connected to the ARP (IC302) through the bus, then they are read and checked. In case of discord, written bit pattern and read data are displayed. If data where multiple bits are 1 are read, the bits concerned may touch each other. Further, if data where certain bit is always 1 or 0 regardless of written data, the line could be disconnected or shorted. (5-4) ARP to RAM Address Bus Data write t other address read discord check Error 10: ARP Tt RAM address bus error Caution: Address and data display in case of an error is different from the display of other diagnosis (described later). Before starting the test, all addresses of RAM (IC303) are cleared to 0x0000. First, 0xA55A is written to the address 0x00000, and the address data are read and checked from addresses 0x00001 to 0x80000 while shifting 1 bit each. Next, the data at that address is cleared, and it is written to the address 0x00001, and read and checked in the same manner. This check is repeated up to the address 0x80000 while shifting the ad- dress data by 1 bit each. If data other than 0 is read at the addresses except written address, an error is given because all addresses were al- ready cleared to 0. In this check, the error display pattern is different from that of other diagnosis; read data, written address, and read address are displayed in this order. How- ever, the message uses same template, and accordingly ex- change Address and Data when reading. The following dis- play, for example, ### Syscon Diagnosis ### 5-4. ARP to RAM Address Bus Error 10: ARP - RAM Address B Address : 0000A55A Write Data : 00000000 Read Data : 00080000 Press NEXT Key to Continue Press PREV key to Repeat _ shows the data 0xA55A was read from address 0x00080000 though it was written to the address 0x00000000. This implies that these addresses are in the form of shadow. Also, if the read data is not 0xA55A, another error will be present. (5-5) ARP RAM Check Data write t read, and accord check Error 11: ARP RAM read data discord The program code data stored in ROM are copied to all areas of RAM (IC303) connected to the ARP through the bus, then they are read and checked if they accord. If the detail check was selected initially, the data are written to all areas and read, then the same test is conducted once again with the data where all bits are inverted between 1 and 0. If discord is detected, faulty address, written data, and read data are displayed following the error code 11, and the test is suspended. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 6-4 6. AV Decoder (6-2) 1935 RAM Data write t read, and accord check Error 14: AVD RAM read data discord The program code data stored in ROM (IC107) are copied to all areas of RAM (IC504, IC505) connected to the AVD through the bus, then they are read and checked if they ac- cord. Further, the same test is conducted once again with the data where all bits are inverted between 1 and 0. If dis- cord is detected, faulty address, written data, and read data are displayed following the error code 14, and the test is suspended. During the test, OSD display becomes blank as the OSD area is also checked. (6-3) 1935 SP ROM t AVD RAM t Video OUT Error: Not detected. The data including sub picture streams in ROM are trans- ferred to the RAM in AVD, and output as video signals from the AVD. Though OSD display becomes blank, the output of video signals continues until the key is pressed. 7. Video Output (7-2) Color Bar AVD color bar command write t Video OUT Error: Not detected. The command is transferred to the AVD, and the color bar signals are output from video terminals. (7-3) Composite Out (European model only) EURO-AV video output check AVD color bar command write t Video (EURO-AV) OUT Error: Not detected. With the component of video output turned off, the color bar signals are output from the EURO-AV terminal. This check is performed for European model only. (7-4) Y/C Out (European model only) Y/C video output check AVD color bar command write t Video (Y/C) OUT Error: Not detected. With the Y/C of video output turned on, the color bar sig- nals are output. This check is performed for European model only. (7-5) RGB Out (European model only) RGB video output check AVD color bar command write t Video (RGB) OUT Error: Not detected. With the RGB of video output turned on, the color bar sig- nals are output. This check is performed for European model only. (7-6) Component Out (European model only) Component video output check AVD color bar command write t Video (Component) OUT Error: Not detected. With the component of video output turned on, the color bar signals are output. This check is performed for European model only. (7-7) Euro AV Through (European model only) AV Through output On/Off Error: Not detected. AV Through output is turned on. This check is performed for European model only. 8. Audio Output (8-2) ARP t1935 Data flow from supply system DRAM to SDRAM of AV Decoder is tested. Error 15: ARP t 1935 video NG 16: ARP t 1935 audio NG (8-3) Test Tone Pink noise output Error: Not detected. In the models without DD output, the test tone is output from L and R of 2-channel only, and in the models with DD output, the test tone is output from L and R of 2-chan- nel, and all channels of 5.1 output. After turning on all outputs, each time the [NEXT] key is pressed, the output channel is switched for individual chan- nel checking. Diagnosis Check Items List 2. Version Display (2-2) Revision (2-3) ROM Check Sum (2-4) Model Type (2-5) Region (2-6) M’t Check 3. Peripheral (3-2) EEPROM Check (3-6) Venc Check (NC655P only) (3-7) ———— (Function not supported) (3-8) External RAM Check (NC655P only) 4. Servo (4-2) Servo DSP Check (4-3) ———— (Function not supported) (4-4) RF Amp Register Check 5. Data Supply System (5-2) ARP Register Check (5-3) ARP to RAM Data Bus (5-4) ARP to RAM Address Bus (5-5) ARP RAM Check 6. AV Decoder (6-2) 1935 RAM (6-3) 1935 SP 7. Video Output (7-2) Color Bar (7-3) Composite Out (European model only) (7-4) Y/C Out (European model only) (7-5) RGB Out (European model only) (7-6) Component Out (European model only) (7-7) Euro AV Through (European model only) 8. Audio Output (8-2) ARP t1935 (8-3) Test Tone www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 6-5 Error Codes List 00: Error not detected 01: RAM write/read data discord 03: EEPROM NG 04: Flash memory clear error 05: Flash memory write error 06: Flash memory read data discord 08: ARP register read data discord 09: ARP Tt RAM data bus error 10: ARP Tt RAM address bus error 11: ARP RAM read data discord 12: Servo DSP NG 13: RF Amp NG 14: 1935 SDRAM NG 15: ARP t1935 video NG 16: ARP t1935 audio NG 1A: System call error (Function not supported) 1B: System call error (Parameter error) 1C: System call error (Illegal ID number) 20: System call error (Time out) 22: Resistor installation error 52: Video Encoder W/R NG 55: External RAM W/R NG 90: Error occurred 91: User verification NG 92: Diagnosis cancelled 6-4. DRIVE AUTO ADJUSTMENT On the Test Mode Menu screen, press [1] key on the remote com- mander, and the drive auto adjustment menu will be displayed. Normally, [0] is selected to adjust DVD (single layer), CD, and DVD (dual layer) in this order. But, individual items can be ad- justed for the case where adjustment is suspended due to an error. In this mode, the adjustment can be made easily through the op- eration following the message displayed on the screen. Which disc is currently adjusted is displayed on the fluorescent display tube. 0. ALL You will be asked if EEPROM data are initialized or not, and for this prompt, select [0] and press the [ENTER] key. First, the servo setting data in EEPROM, Emergency History and Hour Meter are cleared to initialize. Then, [1] DVD-SL disc, [2] CD disc, and [3] DVD-DL disc are adjusted in this order. Because the changer model can accept multiple discs in advance of adjustment, adjustments can be continued by exchanging discs automatically whenever an adjustment is completed following the instruction on screen. You can exit the adjustment by pressing the x button. In adjusting each disc, the mirror time is measured to check the disk type. In the auto adjustment, whether the disc type is correct is not checked unlike conventional models, and accordingly, take care not to in- sert a different type of disc. ## Drive Auto Adjustment ## Adjustment Menu 0. ALL 1. DVD-SL 2. CD 3. DVD-DL 4. LCD Exit: RETURN www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 6-6 1. DVD Single Layer Disc Select [1], insert DVD single layer disc, and press [ENTER] key, and the adjustment will be made through the following steps, then adjusted values will be written to the EEPROM. The table No. 1 is used in the changer type model. If there is no disc on the table No. 1, the tray will be open to wait for closing. If there is a disc on the table, the adjustment starts immediately. If you put a disc prior to adjustment, confirm that the SL disc is set on the table 1. DVD Single Layer Disc Adjustment Steps 1. Sled Reset 2. Disc Check Memory SL 3. Set Disc Type SL 4. Spdl Start 5. Ld ON 6. Focus Error Check 7. Focus ON 0 with PI Level measure 8. Auto Track Offset Adjust L0 9. Trv Level Check 10. Tracking ON 11. CLVA ON 12. Sled ON 13. Auto Focus Balance Adjust 14. Auto Loop Filter Offset Adjust 15. Auto Focus Gain Adjust L0 16. Auto Focus Balance Adjust L0 17. EQ Boost Adjust 18. Auto Loop Filter Offset Adjust 19. Auto Tracking Gain Adjust 20. RF Level Measure 21. Jitter measure 22. Eep Copy Loop Filter Offset 23. All Servo Stop 2. CD Disc Select [2], insert CD disc, and press [ENTER] key, and the adjust- ment will be made through the following steps, then adjusted val- ues will be written to the EEPROM. The table No. 2 is used in the changer type model. If there is no disc on the table No. 2, the tray will be open to wait for closing. If there is a disc on the table, the adjustment starts immediately. If you put a disc prior to adjust- ment, confirm that the CD is set on the table 2. CD Adjustment Steps 1. Sled Reset 2. Disc Check Memory CD 3. Set Disc Type CD 4. Spdl Start 5. LD ON 6. Focus Error Check 7. Fcs ON 1 with PI Level measure 8. Auto Track Offset Adjust L0 9. Trv Level Check 10. Tracking ON 11. CLVA ON 12. Sled ON 13. Auto Focus Balance Adjust 14. Auto Loop Filter Offset Adjust 15. Auto Focus Gain Adjust L0 16. Auto Focus Balance Adjust L0 17. Eq Boost Adjust 18. Auto Loop Filter Offset Adjust 19. Auto Track Gain Adjust 20. Copy Adjustment Data to LCD 21. RF Level Measure 22. Jitter measure 23. All Servo Stop 3. DVD Dual Layer Disc Select [3], insert DVD dual layer disc, and press [ENTER] key, and the adjustment will be made through the following steps, then ad- justed values will be written to the EEPROM. The table No. 3 is used in the changer type model. If there is no disc on the table No. 3, the tray will be open to wait for closing. If there is a disc on the table, the adjustment starts immediately. If you put a disc prior to adjustment, confirm that the DL disc is set on the table 3. DVD Dual Layer Disc Adjustment Steps 1. Sled Reset 2. Disc Check Memory DL 3. Set Disc Type DL DVD DL Layer 1 Adjust 4. Spdl Start 5. LD ON 6. Fcs ON 1 with PI Level measure 7. Auto Track Offset Adjust L1 8. Tracking ON 9. Clva ON 10. Sled ON 11. Auto Focus Balance Adjust 12. Auto Focus Gain Adjust L1 13. Auto Focus Balance Adjust L1 14. Eq Boost Adjust L1 15. Auto Track Gain Adjust L1 16. Jitter measure DVD DL Layer 0 Adjust 17. Focus Jump (L1 t L0) 18. Auto Track Offset Adjust L0 19. Tracking ON 20. Clva ON 21. Sled ON 22. Auto Focus Balance Adjust 23. Auto Focus Gain Adjust L0 24. Auto Focus Balance Adjust 25. Eq Boost Adjust L0 26. Auto Track Gain Adjust L0 27. Jitter measure 28. All Servo Stop 4. LCD LCD disc is not adjusted because the adjusted data of CD are re- flected, and SACD (hybrid disc) is not adjusted because the ad- justed data of CD and DVD-DL are reflected. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 6-7 6-5. DRIVE MANUAL OPERATION On the Test Mode Menu screen, select [2], and the manual opera- tion menu will be displayed. For the manual operation, each servo on/off control and adjustment can be executed manually. In using the Manual Operation menu, take care of the following points. These commands do not provide protection, thus requiring correct operation. The sector address or time code field is dis- played when a disc is loaded. 1. Set correctly the disc type to be used on the Disc Type setting screen. The Disc Type setting must be performed after a disc was loaded. The set Disc Type is cleared when the tray is opened. 2. After power ON, if the Manual Operation was selected, first perform “Reset SLED TILT” by opening 1. Disc Type screen. 3. In case of an alarm, immediately press the x button to stop the servo operation, and turn the power OFF. Basic operation (controllable from front panel or remote com- mander) [POWER] : Power OFF x : Servo stop A (Open/Close) : Stop+Eject/Loading O : Return to Operation Menu or Test Mode Menu > , . : Transition between sub modes of menu [1] to [9], [0] : Selection of menu and items Cursor [Q]/[q] : Increase/Decrease in manually adjusted value 0. Disc Check Memory On this screen, the mirror time is measured and written to the EEPROM to check the disc type. First, set a DVD SL disc and press [1], then set a CD disc and press [2], and finally set a DVD DL disc and press [3]. The measured mirror time is displayed re- spectively. The adjustment must be executed more than once after default data were written. From this screen, you can go to another mode by pressing > or . key, but you cannot enter this mode from another mode. You can enter this mode from the Operation Menu screen only. 1. Disc Type On this screen, select the disc type. To select the disc type, press the number of the loaded disc. The selected disc type is displayed at the bottom. Selecting [1] automatically selects and displays the disc type. In case of wrong display, retry “Disc Check Memory”. Also, opening the tray causes the set disc type to be cleared. In this case, set the disc type again after loading. In performing manual operation, the disc type must be set. ## Drive Manual Operation ## Operation Menu 1. Disc Type 2. Servo Control 3. Track/Layer Jump 4. Manual Adjustment 5. Auto Adjustment 6. Memory Check 0. Disc Check Memory Exit: RETURN Disc Check 1. SL Disc Check 2. CD Disc Check 3. DL Disc Check 0. Reset SLED TILT Disc Type 1. Disc Type Auto Check 2. DVD SL 12cm 3. DVD DL 12cm 4. CD 12cm 5. SACD 12cm 6. DVD SL 8cm 7. DVD DL 8cm 8. CD 8cm 9. LCD 8cm 0. Reset SLED TILT EMG. 00 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 6-8 Once the disc type has been selected, the sector address or time code display field will appear as shown below. These values are displayed when PLL is locked. Display when DVD SL 12cm disc was selected Display when CD 12cm disc was selected [0] Reset SLED TILT: Reset the Sled and Tilt to initial position. (Reset the Sled only to initial position be- cause the Tilt mechanism is not available in this model.) [1] Disc Type Check: Judge automatically the loaded disc. As the judged result is displayed at the bottom of screen, make sure that it is correct. If Disc Check Memory menu has not been executed after EEPROM default setting, the disc type cannot be judged. In this case, return to the initial menu and make a check for three types of discs (SL, DL, CD). [2] to [9]: Select the loaded disc. The adjusted value is written to the address of selected disc. No further entry is necessary if [1] was se- lected. 2. Servo Control On this screen, the servo on/off control necessary for replay is executed. Normally, turn on each servo from 1 sequentially and when CLVA is turned on, the usual trace mode becomes active. In the trace mode, DVD sector address or CD time code is displayed. This is not displayed where the spindle is not locked. The spindle could run overriding the control if the spindle system is faulty or RF is not present. In such a case, do not operate CLVA. [0] Reset SLED TILT: Reset the Sled and Tilt to initial position. (Reset the Sled only to initial position be- cause the Tilt mechanism is not available in this model.) [1] LD: Turn ON/OFF the laser. [2] SP: Turn ON/OFF the spindle. [3] Focus: Search the focus and turn on the focus. [4] TRK.: Turn ON/OFF the tracking servo. [5] Sled: Turn ON/OFF the sled servo. When PLL is not locked (cannot be locked), the sled servo is not turned ON. The display keeps ON.) [6] CLVA: Turn ON/OFF normal servo of spindle servo. [7] FCS. Srch: Apply same voltage as that of focus search to the focus drive to check the focus drive system. 5 Sled FWD: Move the sled outward. Perform this op- eration with the tracking servo turned off. % Sled REV: Move the sled inward. Perform this opera- tion with the tracking servo turned off. Disc Type 1. Disc Type Auto Check 2. DVD SL 12cm 3. DVD DL 12cm 4. CD 12cm 5. SACD 12cm 6. DVD SL 8cm 7. DVD DL 8cm 8. CD 8cm 9. LCD 8cm 0. Reset SLED TILT TC. :: EMG.00 CD 12cm Disc Type 1. Disc Type Auto Check 2. DVD SL 12cm 3. DVD DL 12cm 4. CD 12cm 5. SACD 12cm 6. DVD SL 8cm 7. DVD DL 8cm 8. CD 8cm 9. LCD 8cm 0. Reset SLED TILT SA. SI. EMG.00 DVD SL 12cm Servo Control 1. LD Off R. Sled FWD 2. SP Off L. Sled REV 3. Focus Off 4. TRK. Off 5. Sled Off 6. CLVA Off 7. FCS. Srch Off 0. Reset SLED TILT SA. SI. EMG.00 DVD SL 12cm www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 6-9 3. Track/Layer Jump On this screen, track jump, etc. can be performed. Only for the DVD-DL, the focus jump and layer jump are displayed in the right field. [1] 1Tj FWD: 1-track jump forward. [2] 1Tj REV: 1-track jump reverse. [3] 2Tj FWD: 2-track jump forward. [4] 2Tj REV: 2-track jump reverse. [5] NTj FWD: N-track jump forward. [6] NTj REV: N-track jump reverse. [7] 500Tj FWD: Fine search forward. [8] 500Tj REV: Fine search reverse. [9] 10k/20k FWD: Direct search forward. [0] 10k/20k REV: Direct search reverse. – The following commands are valid for DVD-DL disc only – 5 (L1 t L0): Focus jump (Trk/Sled Servo OFF) forward. % (L0 t L1): Focus jump (Trk/Sled Servo OFF) reverse. $ (L1 t L0): Layer jump (Trk/Sled Servo ON) forward. 4 (L0 t L1): Layer jump (Trk/Sled Servo ON) reverse. 4. Manual Adjustment On this screen, each item can be adjusted manually. Select the desired number [1] to [0] from the remote commander, and cur- rent setting for the selected item will be displayed, then increase or decrease numeric value with $ key or 4 key. This value is stored in the EEPROM. If CLV has been applied, the jitter is dis- played for reference for the adjustment. [1] TRK. Offset: Adjusts tracking offset. [2] Focus Gain: Adjusts focus gain. [3] TRK. Gain: Adjusts track gain. [4] Focus Offset: Adjusts focus offset. [5] Focus Balance: Adjusts focus balance. [6] L.F. Offset: Adjusts loop filter offset. [7] Analog FRSW: Sets select switch of analog feedback circuit. [8] PLL Dac Gain: Adjusts D/A converter gain of PLL. [9] EQ BOOST: Adjusts boost amount of equalizer. [0] GD ADJ: Adjusts group delay amount. Track/Layer Jump 1. 1Tj FWD R. Fj (L1->L0) 2. 1Tj REV L. Fj (L0->L1) 3. 2Tj FWD U. Lj (L1->L0) 4. 2Tj REV D. Lj (L0->L1) 5. NTj FWD 6. NTj REV 7. 500Tj FWD 8. 500Tj REV 9. 10k/20k FWD 0. 10k/20k REV SA. SI. EMG.00 DVD DL 12cm Manual Adjustment:Up/Down 1. TRK. Offset 2. Focus Gain 3. TRK. Gain 4. Focus Offset 5. Focus Balance 6. L.F. Offset 7. Analog FRSW 8. PLL Dac Gain 9. EQ BOOST 0. GD ADJ Adjustment: Up/Down SA. ------ SI. -- EMG. 00 DVD SL 12cm Jitter FF www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 6-10 5. Auto Adjustment On this screen, each item can be adjusted automatically. Select the desired number [1] to [8] from the remote commander, and se- lected item is adjusted automatically. [1] Auto TRK. Offset: Adjusts tracking offset. [2] Auto Focus Balance: Adjusts focus balance. [3] Auto Focus Offset: Adjusts focus offset. [4] Auto Focus Gain: Adjusts focus gain. [5] Auto TRK. Gain: Adjusts track gain. [6] Auto EQ [7] Auto L.F. Offset: Adjusts loop filter offset. [8] Auto Group Delay 6. Memory Check The display image is shown below and three screens in total can be selected. On this screen, current servo adjusted data stored in the EEPROM are displayed. The adjusted data are initialized by pressing the [CLEAR] key, but be careful that they are not recoverable after initialization. Before clearing the adjusted data, make a note of the set data. This screen will also appear if [0] All is selected in the Drive Auto Adjustment. In this case, default setting cannot be made. “THR A&L” data on the second page cannot be changed if default setting is once made. Auto Adjustment 1. Auto TRK. Offset 2. Auto Focus Balance 3. Auto Focus Offset 4. Auto Focus Gain 5. Auto TRK. Gain 6. Auto EQ. 7. Auto L.F. Offset 8. Auto Group Delay SA.04EF905 SI.00 EMG.00 DVD SL 12cm EEPROM DATA 1  DL  CD LCD SL L0 L1 Focus Gain xx xx xx xx xx TRK. Gain xx xx xx xx xx FCS Balnce xx xx xx xx xx Focus Bias xx xx xx xx xx TRV Offset xx xx xx xx xx L.F. Offset xx xx xx xx xx EQ. Boost xx xx xx xx xx _ UP : Last Data DOWN : Next Data CLEAR : Default Set page.1/3 EEPROM DATA 2  DL  CD LCD SL L0 L1 RF Jitter xx -- xx xx xx RF Level xx -- xx -- -- FE Level xx -- xx -- -- FE Balance xx -- xx -- -- TRV.Level xx -- xx -- -- TE Gain xx xx -- -- -- PI Level xx -- xx xx -- _ UP : PREV Data DOWN : Next Data CLEAR : Default Set page.2/3 EEPROM DATA 3  DL  CD LCD SL L0 L1 Analog FRSW xx xx xx xx xx PLL Dac Gain xx xx xx xx xx Mirror Time xx xx xx xx xx _ THR A&L xx xx xx/xx xx xx UP : PREV Data DOWN : First Data CLEAR : Default Set page.3/3 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 6-11 6-6. MECHA AGING On the Test Mode Menu screen, selecting [3] executes the aging of mechanism. First, open the tray and load a disc. Press the H key, and the aging will start. During aging, the number of the re- peat cycle is displayed. Aging can be aborted at any time by press- ing the x key. After the operation has stopped, unload the disc and press again the x key or the O key to return to the Test Mode Menu. 6-7. EMERGENCY HISTORY On the Test Mode Menu screen, selecting [4] displays the infor- mation such as servo emergency history. The history information from last “1” up to “10” can be scrolled with $ key or 4 key. Also, specific information can be displayed by directly entering that number with the ten-key pad from [1] to [9]. (Emergency history code is shown separately.) The upper two lines display the laser ON total hours. Data below minutes are omitted. Clearing History Information Clearing laser hours Press [DISPLAY] and [CLEAR] keys in this order. Both CD and DVD data are cleared. Clearing emergency history Press [TOP MENU] and [CLEAR] keys in this order. Initializing setup data Press [MENU] and [CLEAR] keys in this order. The data have been initialized when “Set Up Initialized” mes- sage is displayed. The EMG. History display screen will be restored soon. 6-8. VERSION INFORMATION The ROM version, region code, OPT type, etc. are displayed if [5] is selected in the Test Mode Menu. The parenthesized hexadeci- mal number in the version number field indicates the checksum value of the ROM. * Note after Downloading After downloading ROM data, sometimes it happens that checksum is not the same as that of ROM data that has been downloaded. In such a case, go back to the menu screen and select “0. Syscon Diagnosis”, then select “1. All” in “2. Version”. If the result of this operation does not give an agreement, it must be either Download error or ROM error. 6-9. VIDEO LEVEL ADJUSTMENT On the Test Mode Menu screen, selecting [6] displays color bars for video level adjustment. During display of color bars, OSD dis- appears but the menu screen will be restored if pressing any key. ### Mecha Aging ### Press OPEN key Abort : STOP key ### EMG. History ### Laser Hours CD xxhxxm DVD xxhxxm 1. 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 2. 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 Select : 1-9 Scroll :UP/DOWN (1: Last EMG.) Exit :RETURN ### Version Infomation ### IF con. Ver.x.xxx(xxxx) Group xx SYScon. Ver.x.xxx(xxxx) Model xx Region 0x Servo DSP Ver:x.xxx AVD ucode Ver:xxxxxxxx OPT TYPE : x LASER Exit : RETURN www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 6-12 6-10. IF CON SELF DIAGNOSTIC FUNCTION 1. IF-91 BOARD (IF CON) TEST MODE The front board test mode is the IF CON self diagnostic mode. The IF CON can diagnose the functions of the front panel boards that the IF CON controls. Normally, the IF CON makes a serial communication with the SYSTEM CONTROL and operates fol- lowing he commands from the SYSTEM CONTROL, but in the Test mode, the IF CON operates independently from the SYS- TEM CONTROL. In the Test mode, the following functions can be checked. 1. Button function 2. Remote commander receiving function 3. SYSTEM CONTROL-IF CON serial communication 4. Click shuttle function 5. Fluorescent display tube lighting check Grid check Anode check 6. LED control function In the Test mode, the set operates same as usual, except voltage monitoring, communication monitoring, display of fluorescent display tube, and LED control. 1. The routine that monitors +3.3 V (P-CONT) of MB-103 board is not provided. 2. The monitoring timer for serial communication with the SYS- TEM CONTROL is not provided. The set is not placed in the Standby mode, even if the communication with SYSTEM CONTROL is normal. 3. Display of fluorescent display tube (normally, display is made following the commands from SYSTEM CONTROL) 4. LED control (normally, control is made following the com- mands from SYSTEM CONTROL) 2. OPERATION OF SELF CHECK MODE The Self Check mode is the function to conduct the basic test to the FL display and DVD panel section. 2-1. Self Check Mode Transition Processing At the AC Power ON after IF CON (IC404) was reset, the input to 10pin (SELF CHECK) is judged and if “Low” is entered, the main unit transits to the Self Check mode. In this port input judgment, the result of 3-time attempts must be same (assuming that the MB- 103 board are not connected). While pressing the [STOP] key on the main unit with the IF CON in STANDBY mode, enter [RETURN] → [DISPLAY] on the remote commander, and the unit transits to the Self Check Mode. The Self Check mode terminates when the IF CON transits to the STANDBY mode. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 6-13 2-2. Operation of Auto Self Check When the Self Check mode becomes active at the AC Power ON or by key input, the test display of the following steps (1) to (4) is repeated. (1) FLD and LED all ON (for 5 seconds) (2) MODEL display (for 2 seconds) (3) Version display (for 2 seconds) (4) ROM creation date display (for 2 seconds) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 6-14 2-3. Each Self Check Function Each Self Check function tests the FLD display, LED display, and key input. 2-3-1. FLD and LED All ON 2-3-1-1.Transition Keys in Self Check Mode • [STOP] key and [OPEN/CLOSE] key on the main unit • [LEFT] key on the main unit and the remote commander 2-3-1-2. Operation and Display In this mode, all LEDs except STANDBY LED and all segments of FLD turn ON. Example of FLD all ON Input IC404: Pin No. (Signal) Voltage [V] Pin ea (AD1) Pin es (AD2) Pin ef (AD4) Pin eg (AD5) Pin eh (AD6) Pin ej (AD7) 0 – 0.2 ENTER TOP MENU * PLAY OPEN/CLOSE POWER LOAD 0.6 – 0.82 DOWN MENU * PAUSE EXCHANGE DISC 5 1/ALL * 1.16 – 1.47 LEFT RETURN * PREV DISC SKIP DISC 4 PREQ 1.8 – 2.12 UP DISPLAY * NEXT – DISC 3 TVS 2.48 – 2.7 RIGHT – – – DISC 2 DISC 1 5.0 – – – – – – 2-3-2. Main Unit Key Name Display and Key Code Display 2-3-2-1. Transition Keys in Self Check Mode • Keys on main unit except keys transited in self check 2-3-2-2. Operation and Display When a key on the main unit is pressed in the Self Check mode, the name of that key is displayed on the FLD. Also, the key name display and the key code display can be switched with the [DISPLAY] key on the remote commander. “NOTHING” is dis- played when nothing is entered. Also, VCD, DVD, and CD seg- ments turn on when a communication error occurred. FLD display (at input of [PLAY] key on the main unit) * : NC655P only www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 6-15 Key code display (at input of [PLAY] key, Key code: 0Ah) At input of faulty voltage When two keys are pressed 2-3-3. Remote Commander Key Name Display and Key Code Display 2-3-3-1. Transition Keys in Self Check Mode Remote commander keys except keys transited in self check 2-3-3-2. Operation and Display When a key on the remote commander is pressed in the Self Check mode, the name of that key is displayed on the FLD. Also, the key name display and the key code display can be switched with the [DISPLAY] key on the remote commander. “NOTHING” is dis- played when nothing is entered. Also, VCD, DVD, and CD seg- ments turn on when a communication error occurred. Remote commander key name display (at input of [PAUSE] key) Remote commander key code display (at input of [PAUSE] key, Key code: 39h) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 6-16 2-3-4. Communication Monitoring Display The communication state is monitored and displayed while the key name on the main unit and the remote commander is displayed. When the communication to the System Controller failed, VCD, DVD, and CD segments turn on. Communication error display (at no key input) Communication error display (at code display without input of the remote commander) 2-3-5. FLD Anode Test Display and SHUTTLE Click Operation Test 2-3-5-1. Transition Keys in Self Check Mode • [RIGHT] on the main unit and the remote commander • SHUTTLE on the remote commander during Anode Test dis- play (This model does not provide JOG/SHUTTLE, and therefore use another DVD remote commander having the JOG/ SHUTTLE) 2-3-5-2. Operation and Display The Self Check mode transits to this mode when [RIGHT] key is entered. Only the first segment of each grid of FLD turns on, and each time the SHUTTLE is entered, the segment of each grid is switched in order. When SHUTTLE input is clockwise, the seg- ment switches in 1 → 2 → 3 direction, or counterclockwise it switches in 3 → 2 → 1 direction. This tests whether each segment turns on individually. Display at the start of Anode Test ↓ (Input in CW direction) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 6-17 2-3-6. FLD Grid Test Display and SHUTTLE Click Operation Test 2-3-6-1. Transition Keys in Self Check Mode • [UP] on the main unit and the remote commander • SHUTTLE on the remote commander during Grid Test display (This model does not provide JOG/SHUTTLE, and therefore use another DVD remote commander having the JOG/ SHUTTLE) 2-3-6-2. Operation and Display The Self Check mode transits to this mode when [UP] key is en- tered. The first grid of FLD all turns on and other grids turn off. Each time the SHUTTLE is entered, the grid is switched in order. When SHUTTLE input is clockwise, the grid switches in 1 → 2 → 3 direction, or counterclockwise it switches in 3 → 2 → 1 direc- tion. This tests whether each grid turns on individually. Display at the start of Grid Test ↓ (Input in CW direction) 2-3-7. LED Test Display 2-3-7-1. Transition Keys in Self Check Mode • [DOWN] on the main unit and the remote commander • SHUTTLE on the remote commander during LED Test display (This model does not provide JOG/SHUTTLE, and therefore use another DVD remote commander having the JOG/ SHUTTLE) 2-3-7-2. Operation and Display LED is switched in order by the input of JOG/SHUTTLE. Also, LED ON/OFF is switched by the input of same key as the function that turns on the LED concerned. FLD display during LED Test 2-3-8. Beep Sound Test (NC655P only) 2-3-8-1. Transition Keys in Self Check Mode • Input of a key on main unit 2-3-8-2. Operation and Display In the Self Check mode, each time a key on the main unit is en- tered, a beep sound of 1kHz (100ms) is generated. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 6-18 a f h g e r p n s c m d j k b ANODE CONNECTION GRID ASSIGNMENT (13G-1G) 15G 14G 13G 12G 11G 10G 9G 8G 7G 6G 5G 4G 3G 2G 1G DISC P1 P2 P3 P4 P5 P6 P7 P8 P9 P10 P11 P12 P13 P14 P15 P16 P17 P18 15G 14G 13G 12G 11G 10G 9G 8G 7G 6G 5G 4G 3G 2G 1G a h j k b f m s g e n p r c d a h j k b f m s g e n p r c d a h j k b f m s g e n p r c d a h j k b f m s g e n p r c d a h j k b f m s g e n p r c d a h j k b f m s g e n p r c d a h j k b f m s g e n p r c d a h j k b f m s g e n p r c d a h j k b f m s g e n p r c d a h j k b f m s g e n p r c d a h j k b f m s g e n p r c d a h j k b f m s g e n p r c d a h j k b f m s g e n p r c d col col col Dp Dp Dp Dp Dp Dp Dp Dp Dp Dp Dp Dp Dp www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 6-19 6-11. TROUBLESHOOTING 6-11-1. Cannot Enter Test Mode You cannot enter the Test mode when either button has been pressed by any reason with the board assembled in the front panel. In this state, the power does not turn on even under normal condition (the unit is kept in standby state), and also no button is active and the remote commander is not accepted. In this case, disconnect the MB-103 board and AV-62 board, and with the SELF CHECK (pin 0) of IF CON (IC404) on the IF-91 board kept in low state, sup- ply AC, and the IF CON self-diagnosis mode will be forcibly acti- vated. The IF CON (IC404) checks the SELF CHECK port only after the power on reset (only at AC supply, not in standby state). If any button is pressed, its name is displayed on the fluorescent display tube. But, if other than “NOTHING” is displayed though no button is pressed, it means that any button has been pressed. 6-11-2. Faults in Test Mode (MB-103 board) 1. The test mode menu is not displayed. 1-1. Board visual check Check that the ICs of SYSCON (IC104), ROM (IC106 or IC107), AVD (IC403), ARP & SERVO (IC301) are working correctly. Check that outside appearance of the ICs is normal. Check that IC pins are not short-circuited. Check that there is no soldering error. Check that outside appearance of the capacitors and resistors is normal. 1-2. Power supply voltage check Check the power voltage of the power connector (CN102). Check the power voltage of SYSCON (IC104). Check the power voltage of ROM (IC106 or IC107). Check the power voltage of AVD (IC403). Check the power voltage of ARP & SERVO (IC301). If the power voltage has any abnormality t Check that the power supply lines are not shorted. Check that there is no soldering error. If any abnormality cannot be found still t Check that each IC is working normally. 1-3. Clock signal check Measure the clock signal frequency at CPUCK (CL101) of SYSCON (IC104) with an oscilloscope. If the 8.25 MHz signal appears. t Check the machine ac- cording to section 1-3-1 If the 33 MHz signal appears. t Check the machine accord- ing to section 1-3-2. If other frequencies are output. R110 and R113 have defective soldering, X101 crystal os- cillator is defective. If the measurement point is fixed to either “H” or “L”. t Observe XFRRST (pin-uh) of SYSCON (IC104) with an oscilloscope. If the measurement point is “L”, check the following items. If the IC has defective soldering, if the IC is short-circuited. If the measurement point is “H”, t Component X101 or SYSCON (IC104) is defective. 1-3-1. When the 8.25 MHz signal appears at CPUCK • Check the XRD, XWRH and CS0X signal. Observe XRD (pin-u;), XWRH (pin-ua), and CS0X (pin-tk) of SYSCON (IC104) with an oscilloscope. If these pins are fixed to either “L” (0V) or “H” (3.3V), or if these pins stay in the center voltage, check the followings. Check if the signal line does not have the defective solder- ing. Check if the signal line is short-circuited with other signal lines. If you cannot find any problem t SYSCON (IC104) is defective. • HA [0 to 21] signal and HD [0 to 15] signal check Observe HA [0 to 21] (pins- Down : 2709 ms OK 02 : Down –> Open : 2277 ms OK 03 : Up –> ExOpen : 2244 ms OK 04 : ExOpen –> Up : 2819 ms OK 05 : Up –> Down : 407 ms OK 06 : Down –> Up : 422 ms OK Push Any Key _ Exit: RETURN ### Mecha Check ### GuideSlit Time (Right) 11 : 1 –> 2 : 139,138 ms OK 12 : 2 –> 3 : 138,137 ms OK 13 : 3 –> 4 : 138,138 ms OK 14 : 4 –> 5 : 139,138 ms OK 15 : 5 –> 1 : 140,139 ms OK Exist Disc : 3 Push Any Key _ Exit: RETURN www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 6-26E 4 TrayCheck (Left) result display After tray check is completed by rotating it in the counter-clock- wise direction, the following display appears. The guide slit time (in units of ms) of each operation segment of tray is displayed. In the right of the time display, judgment if the time is OK or NG is displayed. The ExistDisc indicates the number where disc is located. This judgment of OK or NG is displayed on the FL display tube. If the remote commander [UP] or [DOWN] key is pressed, results of measurement of each operation segment are displayed on FL display. When [NEXT] is pressed, result of the next measurement is displayed. When [PREVIOUS] is pressed, result of the previous measurement is displayed. If any other key is pressed, display returns to the main menu. In the TrayCheck mode, if any key is pressed, display returns to the main menu. ### Mecha Check ### GuideSlit Time (Left) 21 : 1 –> 5 : 139,138 ms OK 22 : 5 –> 4 : 138,137 ms OK 23 : 4 –> 3 : 138,138 ms OK 24 : 3 –> 2 : 139,138 ms OK 25 : 2 –> 1 : 140,139 ms OK Exist Disc : 3 Push Any Key _ Exit: RETURN 3-3. Voltage Check Mode This mode checks the drive voltages of tray and table. Because the full drive voltage is applied to each motor in this mode, do not execute this mode while the mechanism is being connected. When this mode is selected, the following menu appears. When [PLAY] is pressed, AllCheck starts. When [RIGHT] is pressed, the positive (+) voltage is applied to the motors of tray and table. When [LEFT] is pressed, the negative (+) voltage is applied to the motors of tray and table. When [ENTER] is pressed, voltage is stopped to be applied to the motors of tray and table. Press [RETURN] to exit this mode. ### Voltage Check ### RIGHT : MOTOR + LEFT : MOTOR – ENTER : STOP _ Exit: RETURN www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 7-1 SECTION 7 ELECTRICAL ADJUSTMENT DVP-NC615/NC655P In making adjustment, refer to 7-3. Adjustment Related Parts Arrangement. Note: During diagnostic check, the characters and color bars can be seen only with the NTSC monitor. Therefore, for diag-nostic check, use the monitor that supports both NTSC and PAL modes. Use the reference disc for PAL for check, and use the refer-ence disc for NTSC for adjustment. This section describes procedures and instructions necessary for adjusting electrical circuits in this unit. Instruments required: 1) Color monitor TV 2) Oscilloscope 1 or 2 phenomena, band width over 100 MHz, with delay mode 3) Frequency counter (over 8 digits) 4) Digital voltmeter 5) Standard commander (RMT-D143A/D143E/D143P/D144A) 6) DVD reference disc HLX-501 (J-6090-071-A) (dual layer) (NTSC) HLX-503 (J-6090-069-A) (single layer) (NTSC) HLX-504 (J-6090-088-A) (single layer) (NTSC) HLX-505 (J-6090-089-A) (dual layer) (NTSC) HLX-506 (J-6090-077-A) (single layer) (PAL) HLX-507 (J-6090-078-A) (dual layer) (PAL) 7) SACD reference disc HLXA-509 (J-6090-090-A) 8) Extention Cable (J-6090-107-A) HLX-505 (J-6090-089-A) (dual layer) 7-1. POWER SUPPLY ADJUSTMENT 1. Power Supply Check (HS10S1U/HS10S1F Boards) Mode E-E Instrument Digital voltmeter SW +3.3 V Check Test point CN201 pin 7 Specification 3.5 ± 0.2 Vdc EVER +3.3 V Check Test point CN201 pin 0 Specification 3.5 ± 0.2 Vdc SW +5 V Check Test point CN201 pin qa Specification 5.0 ± 0.3 Vdc SW +11 V Check Test point CN201 pin 5,6 Specification 11.0 ± 1.0 Vdc EV –13 V Check Test point CN201 pin 2 Specification –13.0 ± 1.0 Vdc EVER +11 V Check Test point CN201 pin qs Specification 11.2 ± 1.0 Vdc Checking method: 1) Confirm that each voltage satisfies the specification. Note Because the heatsink installed on the power supply board is a part of the primary side, never touch it to avoid electrical shock. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 7-2 7-2. ADJUSTMENT OF VIDEO SYSTEM 1. Video Level Adjustment (MB-103 Board) This adjustment is made to satisfy the NTSC/PAL standard, and if not adjusted correctly, the brightness will be too large or small. Mode Video level adjustment in test mode Signal Color bars Test point LINE OUT (VIDEO) connector (75 Ω terminated) Instrument Oscilloscope Adjusting element NC615: RV401, NC655P: RV501 Specification 1.0 +0.04 Vp-p –0.02 Adjusting method: 1) In the test mode initial menu “6” Video Level Adjustment, set so that color bars are generated. 2) Adjust the RV501 to attain 1.0+0.04 Vp-p. –0.02 Fig. 7-1. Fig. 7-2. 3. Checking S Video Output S-Y Check S-terminal video output. If it is incorrect, pictures will not be displayed correctly in spite of connection to the TV with a S- terminal cable. Mode Video level adjustment in test mode Signal Color bars Test point S VIDEO OUT (S-Y) connector (75 Ω terminated) Instrument Oscilloscope Specification 1.0 ± 0.05 Vp-p Checking method: 1) In the test mode initial menu “6” Video Level Adjustment, set so that color bars are generated. 2) Confirm that the S-Y level is 1.0 ± 0.05 Vp-p. Fig. 7-3. 4. Checking S Video Output S-C This checks whether the S-C satisfies the NTSC/PAL standard. If it is not correct, the colors will be too dark or light. Mode Video level adjustment in test mode Signal Color bars Test point S VIDEO OUT (S-C) connector (75 Ω terminated) Instrument Oscilloscope Specification A = 286 ± 30 mVp-p (NTSC) A = 300 ± 100 mVp-p (PAL) Checking method: 1) In the test mode initial menu “6” Video Level Adjustment, set so that color bars are generated. 2) Confirm that the S-C burst is “A”. Fig. 7-4. 1.0 Vp-p +0.04 –0.02 1.0 ±0.05 Vp-p A 2. Progressive Video Output Level Adjustment (MB-103 Board) This adjusts progressive video output level. If it is incorrect, correct brightness will not be attained when connected to, for instance, projector. Mode Video level adjustment in test mode Signal Color bars Test point COMPONENT VIDEO OUT (Y) connector (75 Ω terminated) Instrument Oscilloscope Adjusting element RV502 Specification 1.0 +0.04 Vp-p –0.02 Adjusting method: 1) In the test mode initial menu “7” Prog Level Adjustment, set so that color bars are generated. 2) Confirm that the Y level is 1.0 +0.04 Vp-p. –0.02 1.0 Vp-p +0.04 –0.02 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 7-3 5. Checking Component Video Output Y (US, Canadian, Australian, PX Model) This checks component video output Y. If it is incorrect, correct brightness will not be attained when connected to, for instance, projector. Mode Video level adjustment in test mode Signal Color bars Test point COMPONENT VIDEO OUT (Y) connector, (75 Ω terminated) Instrument Oscilloscope Specification 1.0 ± 0.05 Vp-p Checking method: 1) In the test mode initial menu “6” Video Level Adjustment, set so that color bars are generated. 2) Confirm that the Y level is 1.0 ± 0.05 Vp-p. Fig. 7-5. 6. Checking Component Video Output B-Y (US, Canadian, Australian, PX Model) This checks component video output B-Y. If it is incorrect, correct colors will not be displayed when connected to, for instance, projector. Mode Video level adjustment in test mode Signal Color bars Test point COMPONENT VIDEO OUT (PB) connector (75 Ω terminated) Instrument Oscilloscope Specification A = 646 ± 50 mVp-p (US,Canadian) A = 700 ± 50 mVp-p (others) Checking method: 1) In the test mode initial menu “6” Video Level Adjustment, set so that color bars are generated. 2) Confirm that the B-Y level is A. 7. Checking Component Video Output R-Y (US, Canadian, Australian, PX Model) This checks component video output R-Y. If it is incorrect, correct colors will not be displayed when connected to, for instance, projector. Mode Video level adjustment in test mode Signal Color bars Test point COMPONENT VIDEO OUT (PR) connector (75 Ω terminated) Instrument Oscilloscope Specification A = 646 ± 50 mVp-p (US,Canadian) A = 700 ± 50 mVp-p (others) Checking method: 1) In the test mode initial menu “6” Video Level Adjustment, set so that color bars are generated. 2) Confirm that the R-Y level is B. Fig. 7-7. 8. Checking RGB Output R (AEP, UK Model) This checks RGB output R. If it is incorrect, pictures will not be displayed correctly in spite of connection to the TV with an EURO AV connecting cord. Mode In test mode, Push [0] for Syscon Diagnosis and push [7] for Video and push [5] for RGB out Signal Color bars Test point LINE 1 (RGB)-TV connector pin qg (75 Ω terminated) Instrument Oscilloscope Specification 700 ± 50 mVp-p Checking method: 1) Confirm that the R level is 700 ± 50 mVp-p. 1.0 ±0.05 Vp-p Fig. 7-6. Fig. 7-8. A B 700 ± 50 mVp-p www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 7-4 9. Checking RGB Output G (AEP, UK Model) This checks RGB output G. If it is incorrect, pictures will not be displayed correctly in spite of connection to the TV with an EURO AV connecting cord. Mode In test mode, Push [0] for Syscon Diagnosis and push [7] for Video and push [5] for RGB out Signal Color bars Test point LINE 1 (RGB)-TV connector pin qa (75 Ω terminated) Instrument Oscilloscope Specification 700 ± 50 mVp-p Checking method: 1) Confirm that the G level is 700 ± 50 mVp-p. Fig. 7-9. 10. Checking RGB Output B (AEP, UK Model) This checks RGB output B. If it is incorrect, pictures will not be displayed correctly in spite of connection to the TV with an EURO AV connecting cord. Mode In test mode, Push [0] for Syscon Diagnosis and push [7] for Video and push [5] for RGB out Signal Color bars Test point LINE 1 (RGB)-TV connector pin 7 (75 Ω terminated) Instrument Oscilloscope Specification 700 ± 50 mVp-p Checking method: 1) Confirm that the B level is 700 ± 50 mVp-p. Fig. 7-10. 700 ± 50 mVp-p 700 ± 50 mVp-p www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 7-5 7-3. ADJUSTMENT RELATED PARTS ARRANGEMENT MB-103 BOARD (Side A) HS10S1U/HS10S1F BOARDS (Side A) RV401 • RV401: NC615 only • RV501, 502 : NC655P only RV501 RV502 IC403 VIDEO LEVEL ADJ COMP OUT CS OUT CN201 1 12 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 7-6E MEMO www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 8-1 SECTION 8 REPAIR PARTS LIST 8-1. EXPLODED VIEWS NOTE: • -XX, -X mean standardized parts, so they may have some differences from the original one. • Items marked “*” are not stocked since they are seldom required for routine service. Some delay should be anticipated when ordering these items. • The mechanical parts with no reference number in the exploded views are not supplied. • Color Indication of Appearance Parts Example: KNOB, BALANCE (WHITE) . . . (RED) ↑ ↑ Parts of Color Cabinet’s Color • Abbreviation CND : Canadian model SP : Singapore model AUS : Australian model The components identified by mark 0or dotted line with mark 0 are critical for safety. Replace only with part number specified. Les composants identifiés par une marque 0 sont critiques pour la sécurité. Ne les remplacer que par une pièce portant le numéro spécifié. DVP-NC615/NC655P www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 8-2 8-1-1. OVERALL SECTION a a b b 1 2 1 1 5 6 7 7 7 7 7 1 1 1 12 8 9 10 13 12 6 4 Front panel section (See page 8-3) Loading section (See page 8-4) 14 3 not supplied not supplied not supplied not supplied not supplied not supplied not supplied NC655P: AEP,UK AEP,UK AEP,UK US,CND 1 3-970-608-01 SUMITITE (B3), +BV 02 1-468-641-11 POWER BLOCK (NC615:US,CND/NC655P) 02 1-468-642-11 POWER BLOCK (NC615:PX,E,AEP,UK,AUS,SP) 3 3-072-138-01 COVER (SANWA), BATTERY (FOR RMT-D143A/D143P/D143E)(NC615) 3 3-073-096-01 COVER (SANWA), BATTERY (FOR RMT-D144A) (NC655P) 4 3-074-717-01 TRAY 5 4-218-252-51 SCREW (+PTPWH M2.6), FLOATING 6 3-070-883-01 SCREW, TAPPING (NC615:US,CND,PX,AUS/NC655P:US):BLACK 6 3-070-883-11 SCREW, TAPPING (NC615:E,AEP,UK,SP/NC655P:US):SILVER 7 3-970-608-51 SUMITITE (B3), +BV 08 1-575-651-21 CORD, POWER (NC615:PX,E,AEP,UK,SP) 08 1-783-531-31 CORD, POWER (NC615:US,CND/NC655P) 08 1-790-588-11 CORD, POWER (NC615:AUS) 9 3-073-182-02 BUSHING, CODE 10 3-073-127-21 CASE, UPPER (NC615:US,CND,PX,AUS/NC655P):BLACK 10 3-073-127-31 CASE, UPPER (NC615:E,AEP,UK,SP/NC655P):SILVER * 12 3-632-494-01 RE-USE CLAMP 13 3-957-819-01 FOOT 14 1-477-126-11 REMOTE COMMANDER (RMT-D143A) (NC615:US,CND,PX,E) 14 1-477-126-21 REMOTE COMMANDER (RMT-D143P) (NC615:AEP,UK) 14 1-477-126-31 REMOTE COMMANDER (RMT-D143E) (NC615:AUS,SP) 14 1-477-127-11 REMOTE COMMANDER (RMT-D144A)(NC655P) Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks Note : The components identified by mark 0 or dotted line with mark 0 are critical for safety. Replace only with part number specified. Note : Les composants identifiés par une marque 0 sont critiques pour la sécurité. Ne les remplacer que par une pièce portant le numéro spécifié. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 8-3 51 3-970-608-11 SUMITITE (B3), +BV (NC655P) 52 1-786-131-11 SWITCH, TACTILE (NC655P) 53 3-073-491-01 KNOB, CURSOR (NC655P:US):SILVER 53 3-073-491-31 KNOB, CURSOR (NC655P:US):BLACK 55 X-3952-282-1 FRONT PANEL ASSY (B-B) (NC615:US,CND,PX,AUS):BLACK 55 X-3952-283-1 FRONT PANEL ASSY (P-B)(NC655P):BLACK 55 X-3952-284-1 FRONT PANEL ASSY (B-S) (NC615:US,E,AEP,UK,SP):SILVER 55 X-3952-420-1 FRONT PANEL ASSY (P-S)(NC655P):SILVER 56 3-943-995-01 EMBLEM (NO.5), SONY (NC615:US,CND,PX,AUS/NC655P):BLACK 56 3-943-995-31 EMBLEM (NO.5), SONY (NC615:US,E,AEP,UK,SP/NC655P):SILVER 57 4-951-620-01 SCREW (2.6X8), +BVTP Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks 51 52 57 57 53 56 55 not supplied not supplied not supplied not supplied not supplied not supplied not supplied 8-1-2. FRONT PANEL SECTION www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 8-4 8-1-3. LOADING SECTION 101 3-073-858-01 COVER, TRAY (P) (NC655P):BLACK 101 3-073-858-11 COVER, TRAY (P) (NC655P):SILVER 101 3-073-858-21 COVER, TRAY (P) (NC615:US,E,AEP,UK,SP):SILVER 101 3-073-859-01 COVER, TRAY (B) (NC615:US,CND,PX,AUS):BLACK 102 3-074-716-01 TABLE 103 7-685-534-19 SCREW +BTP 2.6X8 TYPE2 N-S 104 7-682-544-04 SCREW +P 3X3 105 3-325-697-21 WASHER 106 3-074-725-01 BELT, TD 107 A-6060-640-A UNIT ASSY, TD 108 A-6060-641-A ROLLER ASSY 110 3-074-737-01 PLATE (GUIDE) Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks 104 103 105 106 108 107 101 103 110 102 Chassis section (See page 8-5) not supplied not supplied not supplied 103 110 103 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 8-5 151 3-074-742-01 GEAR (SHAFT) 152 7-621-259-25 SCREW +P 2.6X4 153 4-218-252-51 SCREW (+PTPWH M2.6), FLOATING 154 3-074-745-01 BELT (LOADING) 155 3-074-744-01 GEAR (LOADING A) 156 4-951-619-01 CUSHION (A) 157 X-3952-380-1 ENCODER ASSY 158 3-074-735-01 GEAR (IDLER) 159 3-074-738-01 GEAR (SWING) 160 3-074-741-01 GEAR (LOADING B) 161 3-016-533-01 WASHER (FR), STOPPER 162 3-074-740-01 GEAR (LOADING C) 163 3-074-739-01 COLLAR (SWING) Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks 164 3-074-736-01 GEAR (CHUCK) 165 3-053-847-11 INSULATOR 166 3-074-729-01 SCREW, INS 167 A-6062-709-A KHM-270AAA SERVICE ASSY 169 X-3952-379-1 HOLDER ASSY, BU 170 3-970-608-51 SUMITITE (B3), +BV 171 A-6060-647-A CHUCK ASSY 172 3-074-731-01 SHEET (FFC) 173 3-531-576-11 RIVET 174 3-074-747-01 CLAMP (FFC) 175 7-685-534-19 SCREW +BTP 2.6X8 TYPE2 N-S M901 X-3952-378-1 MOTOR ASSY, LOADING not supplied not supplied not supplied M901 not supplied 151 152 153 158 153 155 154 156 161 163 162 153 166 165 165 165 166 167 166 171 170 169 172 174 175 173 153 164 160 159 157 8-1-4. CHASSIS SECTION www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 8-6 8-2. ELECTRICAL PARTS LIST NOTE: • Due to standardization, replacements in the parts list may be different from the parts specified in the diagrams or the components used on the set. • -XX, -X mean standardized parts, so they may have some difference from the original one. • Items marked “*” are not stocked since they are seldom required for routine service. Some delay should be anticipated when ordering these items. • CAPACITORS: uF: µF • COILS uH: µH • RESISTORS All resistors are in ohms. METAL: metal-film resistor METAL OXIDE: Metal Oxide-film resistor F: nonflammable • SEMICONDUCTORS In each case, u: µ, for example: uA...: µA... , uPA... , µPA... , uPB... , µPB... , uPC... , µPC... , uPD..., µPD... • Abbreviation CND : Canadian model SP : Singapore model AUS : Australian model When indicating parts by reference number, please include the board name. The components identified by mark 0 or dotted line with mark 0 are critical for safety. Replace only with part number specified. Les composants identifiés par une marque 0 sont critiques pour la sécurité. Ne les remplacer que par une pièce portant le numéro spécifié. Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks AV-62CM (U) BOARD, COMPLETE (NC615:US,CND,PX,E,AUS) ************************************** AV-62CM (E) BOARD, COMPLETE (NC615:AEP,UK) ************************************** AV-62CM (GA) BOARD, COMPLETE (NC615:SP) ************************************** AV-62CPM (U) BOARD, COMPLETE (NC655P) ************************************ < CAPACITOR > C101 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C102 1-126-947-11 ELECT 47uF 20% 25V C109 1-163-809-11 CERAMIC CHIP 0.047uF 10% 25V C110 1-126-947-11 ELECT 47uF 20% 16V C111 1-126-947-11 ELECT 47uF 20% 16V C112 1-107-725-11 CERAMIC CHIP 0.1uF 10% 16V C113 1-126-947-11 ELECT 47uF 20% 16V C114 1-107-725-11 CERAMIC CHIP 0.1uF 10% 16V C126 1-126-947-11 ELECT 47uF 20% 16V C203 1-126-947-11 ELECT 47uF 20% 16V (NC615:AEP,UK/NC655P) C204 1-126-947-11 ELECT 47uF 20% 16V C205 1-126-947-11 ELECT 47uF 20% 16V C207 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C208 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C209 1-126-947-11 ELECT 47uF 20% 16V C210 1-163-135-00 CERAMIC CHIP 560PF 5% 50V C211 1-163-135-00 CERAMIC CHIP 560PF 5% 50V C212 1-163-257-11 CERAMIC CHIP 180PF 5% 50V C213 1-163-257-11 CERAMIC CHIP 180PF 5% 50V C214 1-163-257-11 CERAMIC CHIP 180PF 5% 50V C215 1-163-257-11 CERAMIC CHIP 180PF 5% 50V C216 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C217 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C218 1-126-934-11 ELECT 220uF 20% 16V C219 1-126-960-11 ELECT 1uF 20% 50V C220 1-126-947-11 ELECT 47uF 20% 16V C221 1-126-947-11 ELECT 47uF 20% 16V C222 1-126-960-11 ELECT 1uF 20% 50V (NC615:AEP,UK) C225 1-163-259-91 CERAMIC CHIP 220PF 5% 50V (NC615:AEP,UK,SP) C228 1-163-259-91 CERAMIC CHIP 220PF 5% 50V (NC615:AEP,UK,SP) C247 1-126-947-11 ELECT 47uF 20% 16V C249 1-126-924-11 ELECT 330uF 20% 6.3V < CONNECTOR > CN101 1-815-149-11 CONNECTOR, FPC/FFC(1MM PIC)21P (NC615:AEP,UK) CN201 1-815-390-11 CONNECTOR, FFC/FPC 25P CN202 1-506-473-11 PIN, CONNECTOR 8P < DIODE > D101 8-719-067-40 DIODE STZ6.8N-T146 D102 8-719-067-40 DIODE STZ6.8N-T146 (NC655P) D103 8-719-067-40 DIODE STZ6.8N-T146 (NC655P) D104 8-719-067-40 DIODE STZ6.8N-T146 D201 8-719-050-38 DIODE M1MA152WK-T1 D202 8-719-050-37 DIODE M1MA152WA-T1 D203 8-719-050-37 DIODE M1MA152WA-T1 (NC615:AEP,UK) D204 8-719-073-01 DIODE MA111-(K8).S0 < IC > IC101 8-759-662-86 IC NJM79M05DL1A(TE2) IC102 6-701-820-01 IC LA73053-TLM-E (NC655P) IC102 8-759-826-45 IC LA73050-TLM (NC615:US,CND,PX,E,AUS,SP) IC102 8-759-826-46 IC LA73051-TLM (NC615:AEP,UK) IC201 8-759-909-71 IC BA4558F-E2 IC203 8-759-711-59 IC NJM78L05UA-TE1 IC204 8-749-923-04 IC TOTX178 (OPTICAL) (NC615:AEP,UK/NC655P) < JACK > J101 1-815-362-21 JACK, PIN (6P) (LINE OUT(AUDIO 1.2/VIDEO 1.2)) (NC655P) J101 1-815-358-11 JACK, PIN (3P) (LINE OUT(AUDIO/VIDEO)) (NC615) J102 1-815-360-11 JACK, PIN 3P (COMPONENT VIDEO OUT) (NC615:US,CND,PX,E,AUS,SP/NC655P) J103 1-694-484-21 TERMINAL, S (2P.V) (S VIDEO OUT 1.2) (NC655P) J103 1-794-198-11 CONNECTOR, S TERMINAL (S VIDEO OUT) (NC615) J201 1-793-446-21 JACK, PIN 1P (COAXIAL) < SHORT CHIP > JS101 1-216-295-91 SHORT CHIP 0 AV-62 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 8-7 Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks < COIL > L101 1-412-064-11 INDUCTOR 100uH < TRANSISTOR > Q104 8-729-421-19 TRANSISTOR MUN2213T1 Q105 8-729-424-08 TRANSISTOR MUN2111T1 Q108 8-729-216-22 TRANSISTOR 2SA1162-YG-TE85L Q201 8-729-010-25 TRANSISTOR MSD601-RT1 Q202 8-729-421-19 TRANSISTOR MUN2213T1 Q203 8-729-027-53 TRANSISTOR DTC124TKA-T146 Q204 8-729-010-05 TRANSISTOR MSB709-RT1 Q205 8-729-421-19 TRANSISTOR MUN2213T1 (NC615:AEP,UK) Q206 6-550-137-01 TRANSISTOR SD1938(F)-ST(TX).SO Q207 6-550-137-01 TRANSISTOR SD1938(F)-ST(TX).SO Q208 8-729-027-53 TRANSISTOR DTC124TKA-T146 (NC615:AEP,UK) Q209 8-729-010-05 TRANSISTOR MSB709-RT1 (NC615:AEP,UK) Q210 8-729-049-31 TRANSISTOR 2SB710A-RTX Q211 8-729-010-25 TRANSISTOR MSD601-RT1 Q212 8-729-010-05 TRANSISTOR MSB709-RT1 < RESISTOR > R121 1-216-061-91 RES-CHIP 3.3K 5% 1/10W R126 1-216-021-00 METAL CHIP 68 5% 1/10W (NC615:US,CND,PX,E,AUS,SP/NC655P) R127 1-216-021-00 METAL CHIP 68 5% 1/10W (NC615:US,CND,PX,E,AUS,SP/NC655P) R128 1-216-021-00 METAL CHIP 68 5% 1/10W (NC615:US,CND,PX,E,AUS,SP/NC655P) R129 1-216-073-91 RES-CHIP 10K 5% 1/10W R130 1-216-021-00 METAL CHIP 68 5% 1/10W R131 1-216-021-00 METAL CHIP 68 5% 1/10W (NC655P) R132 1-216-021-00 METAL CHIP 68 5% 1/10W R133 1-216-021-00 METAL CHIP 68 5% 1/10W (NC655P) R134 1-216-021-00 METAL CHIP 68 5% 1/10W (NC655P) R135 1-216-021-00 METAL CHIP 68 5% 1/10W R146 1-216-049-11 RES-CHIP 1K 5% 1/10W R157 1-216-049-11 RES-CHIP 1K 5% 1/10W (NC655P) R158 1-216-049-11 RES-CHIP 1K 5% 1/10W (NC655P) R159 1-216-049-11 RES-CHIP 1K 5% 1/10W (NC655P) R202 1-216-033-00 METAL CHIP 220 5% 1/10W R203 1-216-295-91 SHORT CHIP 0 (NC615:AEP,UK/NC655P) R204 1-216-021-00 METAL CHIP 68 5% 1/10W R205 1-216-073-91 RES-CHIP 10K 5% 1/10W R206 1-216-049-11 RES-CHIP 1K 5% 1/10W R207 1-216-049-11 RES-CHIP 1K 5% 1/10W R208 1-216-049-11 RES-CHIP 1K 5% 1/10W R213 1-208-798-11 METAL CHIP 4.7K 0.5% 1/10W R214 1-208-798-11 METAL CHIP 4.7K 0.5% 1/10W R215 1-208-798-11 METAL CHIP 4.7K 0.5% 1/10W R216 1-208-798-11 METAL CHIP 4.7K 0.5% 1/10W R217 1-208-800-11 METAL CHIP 5.6K 0.5% 1/10W R218 1-208-800-11 METAL CHIP 5.6K 0.5% 1/10W R219 1-216-057-00 METAL CHIP 2.2K 5% 1/10W R220 1-216-057-00 METAL CHIP 2.2K 5% 1/10W R221 1-216-057-00 METAL CHIP 2.2K 5% 1/10W R222 1-216-065-91 RES-CHIP 4.7K 5% 1/10W R223 1-216-065-91 RES-CHIP 4.7K 5% 1/10W (NC615:AEP,UK) R224 1-208-800-11 METAL CHIP 5.6K 0.5% 1/10W R225 1-216-057-00 METAL CHIP 2.2K 5% 1/10W R226 1-208-800-11 METAL CHIP 5.6K 0.5% 1/10W R227 1-216-073-91 RES-CHIP 10K 5% 1/10W R228 1-216-073-91 RES-CHIP 10K 5% 1/10W R229 1-216-089-91 RES-CHIP 47K 5% 1/10W R230 1-216-041-00 METAL CHIP 470 5% 1/10W R231 1-216-041-00 METAL CHIP 470 5% 1/10W R232 1-216-073-91 RES-CHIP 10K 5% 1/10W R233 1-216-089-91 RES-CHIP 47K 5% 1/10W R234 1-216-089-91 RES-CHIP 47K 5% 1/10W R235 1-216-073-91 RES-CHIP 10K 5% 1/10W (NC615:AEP,UK) R236 1-216-073-91 RES-CHIP 10K 5% 1/10W (NC615:AEP,UK) R237 1-216-089-91 RES-CHIP 47K 5% 1/10W (NC615:AEP,UK) R238 1-216-065-91 RES-CHIP 4.7K 5% 1/10W (NC615:US,CND,PX,E,AUS,SP/NC655P) R239 1-216-065-91 RES-CHIP 4.7K 5% 1/10W R240 1-216-073-91 RES-CHIP 10K 5% 1/10W (NC615:AEP,UK) R241 1-216-065-91 RES-CHIP 4.7K 5% 1/10W (NC615:AEP,UK) R242 1-216-097-11 RES-CHIP 100K 5% 1/10W R243 1-216-097-11 RES-CHIP 100K 5% 1/10W (NC615:AEP,UK) R244 1-216-041-00 METAL CHIP 470 5% 1/10W (NC655P) R245 1-216-041-00 METAL CHIP 470 5% 1/10W R246 1-216-041-00 METAL CHIP 470 5% 1/10W (NC655P) R247 1-216-041-00 METAL CHIP 470 5% 1/10W R248 1-216-067-00 METAL CHIP 5.6K 5% 1/10W R249 1-216-073-91 RES-CHIP 10K 5% 1/10W R250 1-216-097-11 RES-CHIP 100K 5% 1/10W R251 1-216-105-91 RES-CHIP 220K 5% 1/10W R258 1-216-041-00 METAL CHIP 470 5% 1/10W R259 1-216-073-91 RES-CHIP 10K 5% 1/10W < SWITCH > S101 1-692-989-11 SWITCH, SLIDE (SEL/INT/PROG) (NC655P) ************************************************************ AV-62 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 8-8 Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks CN-158CM (U) BOARD, COMPLETE (NC615) *********************************** CN-158CPM (U) BOARD, COMPLETE (NC655P) ************************************* < CAPACITOR > C301 1-107-725-11 CERAMIC CHIP 0.1uF 10% 16V C302 1-124-234-00 ELECT 22uF 20% 16V C303 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C304 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C305 1-124-234-00 ELECT 22uF 20% 16V C307 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V C308 1-107-725-11 CERAMIC CHIP 0.1uF 10% 16V C309 1-107-725-11 CERAMIC CHIP 0.1uF 10% 16V C310 1-107-725-11 CERAMIC CHIP 0.1uF 10% 16V C315 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C316 1-124-589-11 ELECT 47uF 20% 16V C317 1-125-972-91 ELECT 100uF 20% 16V C318 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C319 1-125-972-91 ELECT 100uF 20% 16V C320 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C335 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C336 1-124-589-11 ELECT 47uF 20% 16V < CONNECTOR > CN301 1-794-196-11 CONNECTOR, FFC/FPC 11P CN303 1-785-696-11 CONNECTOR, FFC/FPC 15P * CN304 1-785-530-11 PIN, CONNECTOR (PC BOARD) 10P CN305 1-506-476-11 PIN, CONNECTOR 11P * CN309 1-506-477-11 PIN, CONNECTOR 12P CN310 1-506-473-11 PIN, CONNECTOR 8P * CN311 1-564-005-11 PIN, CONNECTOR 6P < DIODE > D301 8-719-069-54 DIODE UDZSTE-175.1B < FERRITE BEAD > FB301 1-216-295-91 SHORT CHIP 0 FB302 1-216-295-91 SHORT CHIP 0 FB303 1-216-295-91 SHORT CHIP 0 FB304 1-216-295-91 SHORT CHIP 0 FB305 1-216-295-91 SHORT CHIP 0 FB307 1-216-295-91 SHORT CHIP 0 FB309 1-216-295-91 SHORT CHIP 0 FB310 1-216-295-91 SHORT CHIP 0 FB314 1-469-324-21 FERRITE 0UH FB315 1-469-324-21 FERRITE 0UH FB316 1-469-324-21 FERRITE 0UH FB316 1-469-775-21 FERRITE 0UH FB317 1-469-324-21 FERRITE 0UH FB318 1-469-324-21 FERRITE 0UH FB319 1-469-324-21 FERRITE 0UH < IC > IC301 6-701-875-01 IC LMS8117ADTX-1.8/NOPB IC303 8-759-598-69 IC BA6956AN < IC LINK > 0PS301 1-576-509-21 RINK, IC 0PS302 1-576-508-21 RINK, IC < TRANSISTOR > Q001 8-729-048-28 TRANSISTOR 2SD1766-T100-QR Q002 8-729-424-08 TRANSISTOR MUN2111T1 Q303 8-729-010-25 TRANSISTOR MSD601-RT1 < RESISTOR > R311 1-216-057-00 METAL CHIP 2.2K 5% 1/10W R312 1-216-049-11 RES-CHIP 1K 5% 1/10W R313 1-216-065-91 RES-CHIP 4.7K 5% 1/10W R314 1-216-295-91 SHORT CHIP 0 R321 1-216-073-91 RES-CHIP 10K 5% 1/10W R322 1-216-057-00 METAL CHIP 2.2K 5% 1/10W R323 1-216-057-00 METAL CHIP 2.2K 5% 1/10W R324 1-216-033-00 METAL CHIP 220 5% 1/10W R325 1-216-091-00 METAL CHIP 56K 5% 1/10W R326 1-216-049-11 RES-CHIP 1K 5% 1/10W R327 1-216-025-11 RES-CHIP 100 5% 1/10W ************************************************************ ER-14M BOARD, COMPLETE (NC615:AEP,UK) ************************************ < CAPACITOR > C901 1-126-947-11 ELECT 47uF 20% 16V C902 1-126-947-11 ELECT 47uF 20% 16V C903 1-126-947-11 ELECT 47uF 20% 16V C905 1-126-947-11 ELECT 47uF 20% 16V C907 1-126-947-11 ELECT 47uF 20% 16V C913 1-127-715-91 CERAMIC CHIP 0.22uF 10% 16V C914 1-127-715-91 CERAMIC CHIP 0.22uF 10% 16V C943 1-162-927-11 CERAMIC CHIP 100PF 5% 50V C945 1-162-927-11 CERAMIC CHIP 100PF 5% 50V C962 1-162-927-11 CERAMIC CHIP 100PF 5% 50V C963 1-162-927-11 CERAMIC CHIP 100PF 5% 50V < CONNECTOR > CN901 1-815-387-11 CONNECTOR, FPC/FFC 21P < JACK > CNJ902 1-251-780-11 SOCKET, PIN (21P) < DIODE > D901 8-719-073-01 DIODE MA111-(K8).S0 D907 8-719-050-37 DIODE M1MA152WA-T1 D917 8-719-067-40 DIODE STZ6.8N-T146 D918 8-719-067-40 DIODE STZ6.8N-T146 D919 8-719-067-40 DIODE STZ6.8N-T146 D920 8-719-067-40 DIODE STZ6.8N-T146 D929 8-719-056-82 DIODE UDZ-TE-17-6.2B D930 8-719-977-40 DIODE UDZ-TE-17-13B CN-158 ER-14 Note : The components identified by mark 0 or dotted line with mark 0 are critical for safety. Replace only with part number specified. Note : Les composants identifiés par une marque 0 sont critiques pour la sécurité. Ne les remplacer que par une pièce portant le numéro spécifié. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 8-9 Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks < FERRITE BEAD > FB907 1-414-766-22 FERRITE 0UH FB908 1-414-766-22 FERRITE 0UH FB909 1-414-766-22 FERRITE 0UH FB910 1-414-766-22 FERRITE 0UH < IC > IC901 8-759-826-47 IC LA73052-TLM < JUMPER RESISTOR > JR901 1-216-295-91 SHORT CHIP 0 JR902 1-216-295-91 SHORT CHIP 0 JR905 1-216-295-91 SHORT CHIP 0 JR906 1-216-295-91 SHORT CHIP 0 JR907 1-216-295-91 SHORT CHIP 0 JR908 1-216-295-91 SHORT CHIP 0 JR909 1-216-295-91 SHORT CHIP 0 JR910 1-216-295-91 SHORT CHIP 0 JR911 1-216-295-91 SHORT CHIP 0 JR912 1-216-295-91 SHORT CHIP 0 JR913 1-216-295-91 SHORT CHIP 0 JR914 1-216-295-91 SHORT CHIP 0 JR915 1-216-295-91 SHORT CHIP 0 < COIL > L905 1-412-064-11 INDUCTOR 100uH < TRANSISTOR > Q901 8-729-421-19 TRANSISTOR MUN2213T1 Q902 8-729-010-25 TRANSISTOR MSD601-RT1 Q903 8-729-424-08 TRANSISTOR MUN2111T1 Q906 8-729-421-19 TRANSISTOR MUN2213T1 Q907 8-729-424-08 TRANSISTOR MUN2111T1 Q908 8-729-421-22 TRANSISTOR MUN2211T1 < RESISTOR > R902 1-216-295-91 SHORT CHIP 0 R905 1-216-089-91 RES-CHIP 47K 5% 1/10W R906 1-216-089-91 RES-CHIP 47K 5% 1/10W R907 1-216-089-91 RES-CHIP 47K 5% 1/10W R908 1-216-105-91 RES-CHIP 220K 5% 1/10W R909 1-216-037-00 METAL CHIP 330 5% 1/10W R910 1-216-037-00 METAL CHIP 330 5% 1/10W R911 1-216-037-00 METAL CHIP 330 5% 1/10W R912 1-216-037-00 METAL CHIP 330 5% 1/10W R914 1-216-055-00 METAL CHIP 1.8K 5% 1/10W R915 1-216-045-00 METAL CHIP 680 5% 1/10W R916 1-216-055-00 METAL CHIP 1.8K 5% 1/10W R917 1-216-055-00 METAL CHIP 1.8K 5% 1/10W R918 1-216-021-00 METAL CHIP 68 5% 1/10W R924 1-216-041-00 METAL CHIP 470 5% 1/10W R926 1-216-041-00 METAL CHIP 470 5% 1/10W R927 1-216-021-00 METAL CHIP 68 5% 1/10W R928 1-216-021-00 METAL CHIP 68 5% 1/10W R929 1-216-021-00 METAL CHIP 68 5% 1/10W R939 1-216-017-91 RES-CHIP 47 5% 1/10W R950 1-216-081-00 METAL CHIP 22K 5% 1/10W R957 1-414-233-22 FERRITE 0UH R958 1-414-233-22 FERRITE 0UH R958 1-500-341-21 FERRITE 0UH ************************************************************ FR-187CM (U) COMPL (NC615) ************************** FR-187CPM (U) BOARD, COMPLETE (NC655P) ************************************* < CAPACITOR > C701 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V (NC655P) < CONNECTOR > * CN701 1-695-822-11 CONNECTOR, BOARD TO BOARD 8P (NC655P) CN701 1-750-186-11 CONNECTOR, BOARD TO BOARD 6P (NC615) < DIODE > D701 8-719-056-06 DIODE SLR-342DCT31 (NC655P) D702 8-719-056-07 DIODE SLR-342MCT31 (NC655P) D703 8-719-056-06 DIODE SLR-342DCT31 (NC655P) D704 8-719-056-07 DIODE SLR-342MCT31 (NC655P) D705 8-719-056-06 DIODE SLR-342DCT31 (NC655P) D706 8-719-056-07 DIODE SLR-342MCT31 (NC655P) D709 8-719-056-06 DIODE SLR-342DCT31 (NC655P) D710 8-719-056-07 DIODE SLR-342MCT31 (NC655P) D711 8-719-056-06 DIODE SLR-342DCT31 (NC655P) D712 8-719-056-07 DIODE SLR-342MCT31 (NC655P) D713 8-719-059-98 DIODE SLR-342VCT31 D714 8-719-056-07 DIODE SLR-342MCT31 < IC > IC702 6-701-119-01 IC BU2090F-E2 (NC655P) < TRANSISTOR > Q701 1-801-806-11 TRANSISTOR DTC144EKA-T146 Q702 1-801-806-11 TRANSISTOR DTC144EKA-T146 < RESISTOR > R701 1-216-021-00 METAL CHIP 68 5% 1/10W (NC655P) R702 1-216-021-00 METAL CHIP 68 5% 1/10W (NC655P) R703 1-216-021-00 METAL CHIP 68 5% 1/10W (NC655P) R704 1-216-021-00 METAL CHIP 68 5% 1/10W (NC655P) R705 1-216-081-00 METAL CHIP 22K 5% 1/10W R706 1-216-021-00 METAL CHIP 68 5% 1/10W (NC655P) R707 1-216-071-00 METAL CHIP 8.2K 5% 1/10W R708 1-216-021-00 METAL CHIP 68 5% 1/10W (NC655P) R709 1-216-071-00 METAL CHIP 8.2K 5% 1/10W R710 1-216-063-91 RES-CHIP 3.9K 5% 1/10W ER-14 FR-187 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 8-10 Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks R712 1-216-059-00 METAL CHIP 2.7K 5% 1/10W R713 1-216-063-91 RES-CHIP 3.9K 5% 1/10W R715 1-216-059-00 METAL CHIP 2.7K 5% 1/10W R716 1-216-021-00 METAL CHIP 68 5% 1/10W (NC655P) R717 1-216-021-00 METAL CHIP 68 5% 1/10W (NC655P) R718 1-216-021-00 METAL CHIP 68 5% 1/10W (NC655P) R719 1-216-021-00 METAL CHIP 68 5% 1/10W (NC655P) R720 1-216-081-00 METAL CHIP 22K 5% 1/10W R721 1-216-041-00 METAL CHIP 470 5% 1/10W R722 1-216-021-00 METAL CHIP 68 5% 1/10W R723 1-216-081-00 METAL CHIP 22K 5% 1/10W < SWITCH > S701 1-771-349-21 SWITCH, KEYBOARD (DISC SELECT 2) S702 1-771-349-21 SWITCH, KEYBOARD (DISC SELECT 3) S703 1-771-349-21 SWITCH, KEYBOARD (DISC SELECT 4) S704 1-771-349-21 SWITCH, KEYBOARD (DISC SELECT 5) S705 1-771-349-21 SWITCH, KEYBOARD (ON/STBY) S706 1-771-349-21 SWITCH, KEYBOARD (PICTURE MODE) S707 1-771-349-21 SWITCH, KEYBOARD (SURROUND) S708 1-771-349-21 SWITCH, KEYBOARD (1/ALL) (NC655P) S709 1-771-349-21 SWITCH, KEYBOARD (LOAD) S710 1-771-349-21 SWITCH, KEYBOARD (DISC SELECT 1) ************************************************************ IF-91CM (U) BOARD, COMPLETE (NC615) ********************************** IF-91CPM (U) BOARD, COMPLETE (NC655P) ************************************ < BUZZER > BZ401 1-529-986-11 BUZZER, VOLTAGE (NC655P) < CAPACITOR > C401 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C402 1-124-589-11 ELECT 47uF 20% 16V C403 1-128-499-11 ELECT 220uF 20% 16V C405 1-163-019-00 CERAMIC CHIP 0.0068uF 10% 50V C406 1-163-019-00 CERAMIC CHIP 0.0068uF 10% 50V C407 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V C408 1-128-131-11 ELECT 22uF 20% 50V C410 1-126-157-11 ELECT 10uF 20% 16V C411 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C414 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C415 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C416 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V C417 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V < CONNECTOR > * CN401 1-564-013-11 PIN, CONNECTOR 3P (NC655P) * CN403 1-695-823-11 CONNECTOR, BOARD TO BOARD 8P (NC655P) CN403 1-750-195-11 CONNECTOR, BOARD TO BOARD 6P (NC615) CN405 1-815-412-11 CONNECTOR, FFC/FPC 5P (NC655P) CN407 1-785-696-11 CONNECTOR, FFC/FPC 15P < DIODE > D403 8-719-041-97 DIODE MA113-(TX) D404 8-719-041-97 DIODE MA113-(TX) D406 8-719-041-97 DIODE MA113-(TX) D407 8-719-041-97 DIODE MA113-(TX) D409 8-719-422-62 DIODE MA8062-L-TX < IC > IC403 8-759-684-35 IC S-80830ANUP-EDT-T2 IC404 6-801-260-01 IC 86CK74AFG-3RD5(M IC406 8-749-019-10 IC GP1UD28SXK < COIL > L401 1-408-978-21 INDUCTOR 47uH < FLUORESCENT INDICATOR > ND401 1-518-809-11 INDICATOR TUBE, FLUORESCENT < TRANSISTOR > Q401 8-729-056-46 TRANSISTOR 2SC5053T100Q Q402 8-729-056-46 TRANSISTOR 2SC5053T100Q Q404 8-729-903-46 TRANSISTOR 2SB1132-T100-QR (NC655P) Q407 8-729-027-23 TRANSISTOR DTA114EKA-T146 (NC655P) < RESISTOR > R401 1-216-065-91 RES-CHIP 4.7K 5% 1/10W (NC655P) R406 1-216-097-11 RES-CHIP 100K 5% 1/10W R407 1-216-017-91 RES-CHIP 47 5% 1/10W R410 1-216-069-00 METAL CHIP 6.8K 5% 1/10W R416 1-216-057-00 METAL CHIP 2.2K 5% 1/10W (NC655P) R417 1-216-073-91 RES-CHIP 10K 5% 1/10W (NC655P) R420 1-216-013-00 METAL CHIP 33 5% 1/10W R422 1-216-025-11 RES-CHIP 100 5% 1/10W R423 1-216-097-11 RES-CHIP 100K 5% 1/10W R424 1-216-295-91 SHORT CHIP 0 (NC615) R425 1-216-027-00 METAL CHIP 120 5% 1/10W R426 1-216-295-91 SHORT CHIP 0 R427 1-216-097-11 RES-CHIP 100K 5% 1/10W (NC655P) R428 1-216-097-11 RES-CHIP 100K 5% 1/10W R430 1-216-025-11 RES-CHIP 100 5% 1/10W R431 1-216-097-11 RES-CHIP 100K 5% 1/10W R433 1-216-097-11 RES-CHIP 100K 5% 1/10W R436 1-216-081-00 METAL CHIP 22K 5% 1/10W R437 1-216-097-11 RES-CHIP 100K 5% 1/10W R438 1-216-073-91 RES-CHIP 10K 5% 1/10W R439 1-216-073-91 RES-CHIP 10K 5% 1/10W R440 1-216-073-91 RES-CHIP 10K 5% 1/10W R441 1-216-073-91 RES-CHIP 10K 5% 1/10W R442 1-216-073-91 RES-CHIP 10K 5% 1/10W R443 1-216-065-91 RES-CHIP 4.7K 5% 1/10W (NC655P) IF-91 FR-187 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 8-11 Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks R444 1-216-065-91 RES-CHIP 4.7K 5% 1/10W (NC655P) R445 1-216-059-00 METAL CHIP 2.7K 5% 1/10W (NC655P) R446 1-216-059-00 METAL CHIP 2.7K 5% 1/10W R447 1-216-059-00 METAL CHIP 2.7K 5% 1/10W R448 1-216-063-91 RES-CHIP 3.9K 5% 1/10W (NC655P) R449 1-216-063-91 RES-CHIP 3.9K 5% 1/10W R450 1-216-063-91 RES-CHIP 3.9K 5% 1/10W R451 1-216-071-00 METAL CHIP 8.2K 5% 1/10W (NC655P) R453 1-216-071-00 METAL CHIP 8.2K 5% 1/10W R456 1-216-295-91 SHORT CHIP 0 R457 1-216-025-11 RES-CHIP 100 5% 1/10W R458 1-216-025-11 RES-CHIP 100 5% 1/10W R459 1-216-025-11 RES-CHIP 100 5% 1/10W R460 1-216-025-11 RES-CHIP 100 5% 1/10W R461 1-216-025-11 RES-CHIP 100 5% 1/10W R462 1-216-025-11 RES-CHIP 100 5% 1/10W R463 1-216-081-00 METAL CHIP 22K 5% 1/10W R464 1-216-073-91 RES-CHIP 10K 5% 1/10W < SWITCH > S401 1-771-349-21 SWITCH, KEYBOARD (STOP) S402 1-771-349-21 SWITCH, KEYBOARD (TOP MENU) (NC655P) S403 1-771-349-21 SWITCH, KEYBOARD (OPEN) S404 1-771-349-21 SWITCH, KEYBOARD (PLAY) S405 1-771-349-21 SWITCH, KEYBOARD (MENU) (NC655P) S406 1-771-349-21 SWITCH, KEYBOARD (EXCHANGE) S407 1-771-349-21 SWITCH, KEYBOARD (PAUSE) S408 1-771-349-21 SWITCH, KEYBOARD (RETURN) (NC655P) S409 1-771-349-21 SWITCH, KEYBOARD (DISC SKIP) S410 1-771-349-21 SWITCH, KEYBOARD (PREV) S413 1-771-349-21 SWITCH, KEYBOARD (NEXT) S414 1-771-349-21 SWITCH, KEYBOARD (DISPLAY) (NC655P) < TRANSFORMER > T401 1-437-655-11 TRANSFORMER, DC-DC CONVERTER < VIBRATOR > X401 1-781-472-21 VIBRATOR, CERAMIC (Hz) ************************************************************ MB-103CM (UC) BOARD, COMPLETE (NC615:US,CND,PX) ************************************** MB-103CM (LA) BOARD, COMPLETE (NC615:E) ************************************** MB-103CM (E1) BOARD, COMPLETE (NC615:AEP,UK) ************************************** MB-103CM (OC) BOARD, COMPLETE (NC615:AUS) ************************************** MB-103CM (GA) BOARD, COMPLETE (NC615:SP) ************************************** MB-103CPM (U) BOARD, COMPLETE (NC655P) ************************************* < CAPACITOR > C102 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C103 1-126-209-11 ELECT CHIP 100uF 20% 4V C104 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C105 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C106 1-162-916-11 CERAMIC CHIP 12PF 5% 50V C107 1-162-917-11 CERAMIC CHIP 15PF 5% 50V C108 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C109 1-126-209-11 ELECT CHIP 100uF 20% 4V C110 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C111 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C114 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C118 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C120 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C121 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C122 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C125 1-126-607-11 ELECT CHIP 47uF 20% 4V C126 1-126-206-11 ELECT CHIP 100uF 20% 6.3V C127 1-126-204-11 ELECT CHIP 47uF 20% 16V C128 1-126-246-11 ELECT CHIP 220uF 20% 4V C129 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C130 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V (NC655P) C201 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C202 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C203 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C204 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C206 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C210 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V C211 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V C212 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V C213 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V C214 1-164-245-11 CERAMIC CHIP 0.015uF 10% 25V C215 1-162-927-11 CERAMIC CHIP 100PF 5% 50V C216 1-164-230-11 CERAMIC CHIP 220PF 5% 50V C218 1-162-965-11 CERAMIC CHIP 0.0015uF 10% 50V C219 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C220 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C221 1-124-779-00 ELECT CHIP 10uF 20% 16V C225 1-162-927-11 CERAMIC CHIP 100PF 5% 50V C226 1-164-230-11 CERAMIC CHIP 220PF 5% 50V C228 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C229 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C230 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V C232 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V C233 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V C234 1-126-205-11 ELECT CHIP 47uF 20% 6.3V C235 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C236 1-164-739-11 CERAMIC CHIP 560PF 5% 50V C238 1-124-779-00 ELECT CHIP 10uF 20% 16V C240 1-164-677-11 CERAMIC CHIP 0.033uF 10% 16V C241 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C242 1-126-205-11 ELECT CHIP 47uF 20% 6.3V C243 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C244 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C245 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C246 1-164-677-11 CERAMIC CHIP 0.033uF 10% 16V MB-103 IF-91 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 8-12 Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks C247 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C248 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C249 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C250 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C251 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C252 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C253 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C254 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C255 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C256 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V C257 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V C258 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C259 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C260 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C261 1-162-959-11 CERAMIC CHIP 330PF 5% 50V C262 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C263 1-124-779-00 ELECT CHIP 10uF 20% 16V C264 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C265 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C266 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C270 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C271 1-126-204-11 ELECT CHIP 47uF 20% 16V C272 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C273 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C304 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C305 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V C308 1-126-206-11 ELECT CHIP 100uF 20% 6.3V C309 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C310 1-162-927-11 CERAMIC CHIP 100PF 5% 50V C311 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C312 1-110-563-11 CERAMIC CHIP 0.068uF 10% 16V C313 1-164-677-11 CERAMIC CHIP 0.033uF 10% 16V C314 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C315 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C316 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V C317 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C318 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V C319 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C320 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V C321 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C322 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C323 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C324 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C325 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C326 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C327 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C328 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C329 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C330 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V C331 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C332 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C333 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C334 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C335 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C337 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C338 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C339 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C340 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C343 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C344 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C401 1-124-779-00 ELECT CHIP 10uF 20% 16V (NC615) C402 1-124-779-00 ELECT CHIP 10uF 20% 16V C403 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V (NC615) C404 1-126-193-11 ELECT 1uF 20% 50V C405 1-126-246-11 ELECT CHIP 220uF 20% 4V (NC615) C406 1-124-779-00 ELECT CHIP 10uF 20% 16V C407 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C408 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C410 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C412 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C413 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C415 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C416 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C417 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C418 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C419 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C420 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V (NC615) C422 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C423 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C425 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C426 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C428 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C429 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C431 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C432 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C435 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C436 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C438 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C439 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C441 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V (NC615:AEP,UK,AUS,SP/NC655P) C442 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V (NC615:AEP,UK,AUS,SP/NC655P) C446 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C447 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V (NC615:AEP,UK,AUS,SP/NC655P) C449 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C501 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V (NC655P) C502 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V (NC655P) C503 1-126-205-11 ELECT CHIP 47uF 20% 6.3V (NC655P) C504 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V (NC655P) C505 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V (NC655P) C506 1-126-205-11 ELECT CHIP 47uF 20% 6.3V (NC655P) C507 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V (NC655P) C508 1-126-205-11 ELECT CHIP 47uF 20% 6.3V (NC655P) C509 1-126-205-11 ELECT CHIP 47uF 20% 6.3V (NC655P) C510 1-126-205-11 ELECT CHIP 47uF 20% 6.3V (NC655P) C511 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V (NC655P) MB-103 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 8-13 Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks C512 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V (NC655P) C513 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V (NC655P) C514 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V (NC655P) C515 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V (NC655P) C516 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V (NC655P) C517 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V (NC655P) C518 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V (NC655P) C520 1-126-205-11 ELECT CHIP 47uF 20% 6.3V (NC655P) C521 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V (NC655P) C526 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V (NC655P) C527 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V (NC655P) C528 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V (NC655P) C529 1-127-715-91 CERAMIC CHIP 0.22uF 10% 16V (NC655P) C531 1-127-715-91 CERAMIC CHIP 0.22uF 10% 16V (NC655P) C532 1-164-315-11 CERAMIC CHIP 470PF 5% 50V (NC655P) C533 1-164-315-11 CERAMIC CHIP 470PF 5% 50V (NC655P) C534 1-164-173-11 CERAMIC CHIP 0.0039uF 10% 50V (NC655P) C537 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V (NC655P) C538 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V (NC655P) C539 1-164-733-11 CERAMIC CHIP 820PF 10% 50V (NC655P) C540 1-127-715-91 CERAMIC CHIP 0.22uF 10% 16V (NC655P) C541 1-126-205-11 ELECT CHIP 47uF 20% 6.3V (NC655P) C542 1-127-715-91 CERAMIC CHIP 0.22uF 10% 16V (NC655P) C543 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V (NC655P) C544 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V (NC655P) C545 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V (NC655P) C546 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V (NC655P) C602 1-127-715-91 CERAMIC CHIP 0.22uF 10% 16V C603 1-124-779-00 ELECT CHIP 10uF 20% 16V C604 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V < CONNECTOR > * CN102 1-770-154-11 PIN, CONNECTOR (PC BOARD) 6P * CN103 1-770-470-21 PIN, CONNECTOR (PC BOARD) 6P CN203 1-815-507-21 CONNECTOR, FFC/FPC 26P < FERRITE BEAD > FB103 1-469-324-21 FERRITE 0UH FB104 1-469-324-21 FERRITE 0UH FB105 1-469-324-21 FERRITE 0UH FB106 1-469-324-21 FERRITE 0UH FB107 1-469-324-21 FERRITE 0UH FB108 1-469-324-21 FERRITE 0UH FB109 1-469-324-21 FERRITE 0UH FB111 1-469-324-21 FERRITE 0UH FB602 1-414-226-21 FERRITE 0UH (NC615) FB603 1-414-226-21 FERRITE 0UH (NC615) < FILTER > FL108 1-234-177-21 FERRITE 0UH (NC655P) FL101 1-234-177-21 FERRITE 0UH FL102 1-234-177-21 FERRITE 0UH FL103 1-234-177-21 FERRITE 0UH FL104 1-234-177-21 FERRITE 0UH FL105 1-234-177-21 FERRITE 0UH FL106 1-234-177-21 FERRITE 0UH FL109 1-233-893-21 FILTER, CHIP EMI FL110 1-234-177-21 FERRITE 0UH FL201 1-234-177-21 FERRITE 0UH FL402 1-234-177-21 FERRITE 0UH FL403 1-234-177-21 FERRITE 0UH FL404 1-234-177-21 FERRITE 0UH < IC > IC101 8-759-641-86 IC BR24C16F-E2 (NC615) IC101 8-759-643-29 IC BR24C64F-E2 (NC655P) IC103 6-701-879-01 IC CY24233ZCT IC104 6-701-837-01 IC MB91307RPFV-G-BND-E1 IC107 6-802-250-01 IC MR27V3202F-7NTPZ04B (NC615:US,CND,E,PX) IC107 6-802-251-01 IC MR27V3202F-7PTPZ04B (EXCEPT NC615:US,CND,E,PX) IC107 6-802-253-01 IC MR27V3202F-7STPZ04B (NC655P) IC108 6-701-874-01 IC IDT71V016SA15PH8(SCD2994) (NC655P) IC201 6-701-700-01 IC SP3728ACB IC202 6-701-878-01 IC FAN8034L IC301 6-701-876-01 IC CXD9703R IC302 8-759-599-45 IC MM1385ENLE IC303 6-701-969-01 IC K4F151612D-UL60T IC401 6-702-300-01 IC TK11118CSCL-G IC402 8-759-599-45 IC MM1385ENLE (NC615) IC403 8-752-416-45 IC CXD1935Q IC404 6-700-353-01 IC MT48LC1M16A1TG-6STR IC405 6-700-353-01 IC MT48LC1M16A1TG-6STR (NC615:AEP,UK,AUS,SP/NC655P) IC501 8-759-588-58 IC MM1385NNLE (NC655P) IC502 6-701-814-01 IC CXD9698R (NC655P) IC503 6-700-353-01 IC MT48LC1M16A1TG-6STR (NC655P) IC504 6-701-079-01 IC ADV7300AKST (NC655P) IC505 8-759-588-58 IC MM1385NNLE (NC655P) IC601 6-701-565-01 IC CXD9627A-E2 MB-103 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 8-14 Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks < COIL > L101 1-414-410-21 INDUCTOR 10uH L201 1-412-031-11 INDUCTOR CHIP 47uH L202 1-412-031-11 INDUCTOR CHIP 47uH < TRANSISTOR > Q201 8-729-903-46 TRANSISTOR 2SB1132-T100-QR Q202 8-729-903-46 TRANSISTOR 2SB1132-T100-QR < RESISTOR > R103 1-216-809-11 METAL CHIP 100 5% 1/10W R104 1-216-809-11 METAL CHIP 100 5% 1/10W R105 1-216-809-11 METAL CHIP 100 5% 1/10W R106 1-216-809-11 METAL CHIP 100 5% 1/10W R108 1-216-789-11 METAL CHIP 2.2 5% 1/10W R110 1-216-821-11 METAL CHIP 1K 5% 1/10W R111 1-216-809-11 METAL CHIP 100 5% 1/10W R112 1-216-809-11 METAL CHIP 100 5% 1/10W R113 1-216-837-11 METAL CHIP 22K 5% 1/10W R114 1-216-821-11 METAL CHIP 1K 5% 1/10W R116 1-216-801-11 METAL CHIP 22 5% 1/10W R117 1-216-821-11 METAL CHIP 1K 5% 1/10W R118 1-216-845-11 METAL CHIP 100K 5% 1/10W R119 1-216-845-11 METAL CHIP 100K 5% 1/10W R120 1-216-821-11 METAL CHIP 1K 5% 1/10W R121 1-216-821-11 METAL CHIP 1K 5% 1/10W R123 1-216-833-11 METAL CHIP 10K 5% 1/10W R124 1-216-833-11 METAL CHIP 10K 5% 1/10W R128 1-216-809-11 METAL CHIP 100 5% 1/10W R129 1-216-809-11 METAL CHIP 100 5% 1/10W R130 1-216-809-11 METAL CHIP 100 5% 1/10W R131 1-216-809-11 METAL CHIP 100 5% 1/10W R132 1-216-864-11 METAL CHIP 0 R133 1-216-864-11 METAL CHIP 0 R134 1-216-801-11 METAL CHIP 22 5% 1/10W R136 1-216-801-11 METAL CHIP 22 5% 1/10W R137 1-216-801-11 METAL CHIP 22 5% 1/10W R139 1-216-827-11 METAL CHIP 3.3K 5% 1/10W R141 1-216-833-11 METAL CHIP 10K 5% 1/10W R150 1-216-833-11 METAL CHIP 10K 5% 1/10W R156 1-216-833-11 METAL CHIP 10K 5% 1/10W R157 1-216-864-11 METAL CHIP 0 5% 1/10W R159 1-216-864-11 METAL CHIP 0 5% 1/10W R160 1-216-864-11 METAL CHIP 0 5% 1/10W R161 1-216-829-11 METAL CHIP 4.7K 5% 1/10W (NC655P) R162 1-216-827-11 METAL CHIP 3.3K 5% 1/10W (NC615) R163 1-216-827-11 METAL CHIP 3.3K 5% 1/10W R164 1-216-041-00 METAL CHIP 470 5% 1/10W (NC615:AUS) R164 1-216-081-00 METAL CHIP 22K 5% 1/10W (NC615:E) R164 1-216-057-00 METAL CHIP 2.2K 5% 1/10W (NC615:SP) R164 1-216-075-00 METAL CHIP 12K 5% 1/10W (NC615:AEP,UK) R165 1-216-827-11 METAL CHIP 3.3K 5% 1/10W R166 1-216-089-91 RES-CHIP 47K 5% 1/10W (NC655P) R168 1-216-827-11 METAL CHIP 3.3K 5% 1/10W R169 1-216-075-00 METAL CHIP 12K 5% 1/10W (NC615:E,AUS) R169 1-216-081-00 METAL CHIP 22K 5% 1/10W (NC615:SP) R169 1-216-089-91 RES-CHIP 47K 5% 1/10W (NC615:AEP,UK) R176 1-216-864-11 METAL CHIP 0 R177 1-216-833-11 METAL CHIP 10K 5% 1/10W R178 1-216-833-11 METAL CHIP 10K 5% 1/10W R180 1-216-809-11 METAL CHIP 100 5% 1/10W R181 1-216-864-11 METAL CHIP 0 R182 1-216-809-11 METAL CHIP 100 5% 1/10W R183 1-216-809-11 METAL CHIP 100 5% 1/10W R184 1-216-833-11 METAL CHIP 10K 5% 1/10W R185 1-216-821-11 METAL CHIP 1K 5% 1/10W R187 1-216-864-11 METAL CHIP 0 R201 1-216-813-11 METAL CHIP 220 5% 1/10W R202 1-216-813-11 METAL CHIP 220 5% 1/10W R203 1-216-821-11 METAL CHIP 1K 5% 1/10W R204 1-216-821-11 METAL CHIP 1K 5% 1/10W R205 1-216-821-11 METAL CHIP 1K 5% 1/10W R206 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R207 1-216-809-11 METAL CHIP 100 5% 1/10W R210 1-216-815-11 METAL CHIP 330 5% 1/10W R211 1-216-809-11 METAL CHIP 100 5% 1/10W R212 1-216-809-11 METAL CHIP 100 5% 1/10W R213 1-216-833-11 METAL CHIP 10K 5% 1/10W R214 1-216-833-11 METAL CHIP 10K 5% 1/10W R215 1-216-833-11 METAL CHIP 10K 5% 1/10W R216 1-216-821-11 METAL CHIP 1K 5% 1/10W R217 1-216-821-11 METAL CHIP 1K 5% 1/10W R218 1-216-846-11 METAL CHIP 120K 5% 1/10W R219 1-216-846-11 METAL CHIP 120K 5% 1/10W R220 1-216-847-11 METAL CHIP 150K 5% 1/10W R221 1-216-847-11 METAL CHIP 150K 5% 1/10W R222 1-216-842-11 METAL CHIP 56K 5% 1/10W R223 1-216-842-11 METAL CHIP 56K 5% 1/10W R224 1-216-850-11 METAL CHIP 270K 5% 1/10W R225 1-216-833-11 METAL CHIP 10K 5% 1/10W R226 1-216-853-11 METAL CHIP 470K 5% 1/10W R227 1-216-846-11 METAL CHIP 120K 5% 1/10W R229 1-216-833-11 METAL CHIP 10K 5% 1/10W R230 1-216-839-11 METAL CHIP 33K 5% 1/10W R231 1-216-855-11 METAL CHIP 680K 5% 1/10W R232 1-216-839-11 METAL CHIP 33K 5% 1/10W R233 1-216-853-11 METAL CHIP 470K 5% 1/10W R234 1-216-803-11 METAL CHIP 33 5% 1/10W R235 1-216-809-11 METAL CHIP 100 5% 1/10W R236 1-216-803-11 METAL CHIP 33 5% 1/10W R238 1-216-839-11 METAL CHIP 33K 5% 1/10W R239 1-216-839-11 METAL CHIP 33K 5% 1/10W R240 1-216-839-11 METAL CHIP 33K 5% 1/10W R241 1-216-839-11 METAL CHIP 33K 5% 1/10W R242 1-216-849-11 METAL CHIP 220K 5% 1/10W MB-103 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 8-15 Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks R243 1-216-853-11 METAL CHIP 470K 5% 1/10W R244 1-216-821-11 METAL CHIP 1K 5% 1/10W R245 1-216-841-11 METAL CHIP 47K 5% 1/10W R246 1-216-809-11 METAL CHIP 100 5% 1/10W R248 1-216-803-11 METAL CHIP 33 5% 1/10W R249 1-216-803-11 METAL CHIP 33 5% 1/10W R250 1-218-895-11 METAL CHIP 100K 0.5% 1/10W R251 1-216-841-11 METAL CHIP 47K 5% 1/10W R252 1-216-839-11 METAL CHIP 33K 5% 1/10W R253 1-218-889-11 METAL CHIP 56K 0.5% 1/10W R254 1-218-895-11 METAL CHIP 100K 0.5% 1/10W R255 1-218-889-11 METAL CHIP 56K 0.5% 1/10W R256 1-216-809-11 METAL CHIP 100 5% 1/10W R259 1-216-833-11 METAL CHIP 10K 5% 1/10W R260 1-216-834-11 METAL CHIP 12K 5% 1/10W R261 1-216-833-11 METAL CHIP 10K 5% 1/10W R262 1-216-815-11 METAL CHIP 330 5% 1/10W R263 1-216-861-11 METAL CHIP 2.2M 5% 1/10W R264 1-216-845-11 METAL CHIP 100K 5% 1/10W R265 1-216-838-11 METAL CHIP 27K 5% 1/10W R269 1-216-833-11 METAL CHIP 10K 5% 1/10W R271 1-216-841-11 METAL CHIP 47K 5% 1/10W R273 1-216-864-11 METAL CHIP 0 R274 1-216-841-11 METAL CHIP 47K 5% 1/10W R280 1-216-864-11 METAL CHIP 0 R301 1-216-295-91 SHORT CHIP 0 R302 1-216-295-91 SHORT CHIP 0 R303 1-216-821-11 METAL CHIP 1K 5% 1/10W R311 1-216-809-11 METAL CHIP 100 5% 1/10W R312 1-218-831-11 METAL CHIP 220 0.5% 1/10W R313 1-216-817-11 METAL CHIP 470 5% 1/10W R314 1-216-817-11 METAL CHIP 470 5% 1/10W R315 1-216-817-11 METAL CHIP 470 5% 1/10W R316 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R317 1-216-833-11 METAL CHIP 10K 5% 1/10W R318 1-216-817-11 METAL CHIP 470 5% 1/10W R319 1-218-871-11 METAL CHIP 10K 0.5% 1/10W R320 1-218-883-11 METAL CHIP 33K 0.5% 1/10W R321 1-218-879-11 METAL CHIP 22K 0.5% 1/10W R322 1-218-847-11 METAL CHIP 1K 0.5% 1/10W R323 1-218-855-11 METAL CHIP 2.2K 0.5% 1/10W R324 1-216-833-11 METAL CHIP 10K 5% 1/10W R325 1-218-867-11 RES-CHIP 6.8K 5% 1/10W R326 1-216-833-11 METAL CHIP 10K 5% 1/10W R327 1-218-871-11 METAL CHIP 10K 0.5% 1/10W R328 1-216-838-11 METAL CHIP 27K 5% 1/10W R329 1-216-825-11 METAL CHIP 2.2K 5% 1/10W R330 1-216-825-11 METAL CHIP 2.2K 5% 1/10W R331 1-216-825-11 METAL CHIP 2.2K 5% 1/10W R332 1-216-825-11 METAL CHIP 2.2K 5% 1/10W R333 1-216-847-11 METAL CHIP 150K 5% 1/10W R334 1-218-853-11 METAL CHIP 1.8K 0.5% 1/10W R335 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R336 1-216-833-11 METAL CHIP 10K 5% 1/10W R346 1-216-833-11 METAL CHIP 10K 5% 1/10W R347 1-216-833-11 METAL CHIP 10K 5% 1/10W R348 1-216-833-11 METAL CHIP 10K 5% 1/10W R349 1-216-833-11 METAL CHIP 10K 5% 1/10W R351 1-216-295-91 SHORT CHIP 0 R352 1-216-295-91 SHORT CHIP 0 R358 1-216-833-11 METAL CHIP 10K 5% 1/10W R359 1-216-833-11 METAL CHIP 10K 5% 1/10W R360 1-216-809-11 METAL CHIP 100 5% 1/10W R401 1-216-295-91 SHORT CHIP 0 (NC615) R402 1-216-295-91 SHORT CHIP 0 R403 1-216-817-11 METAL CHIP 470 5% 1/10W (NC615) R405 1-216-809-11 METAL CHIP 100 5% 1/10W R406 1-218-831-11 METAL CHIP 220 0.5% 1/10W (NC615) R407 1-218-831-11 METAL CHIP 220 0.5% 1/10W (NC615) R408 1-218-831-11 METAL CHIP 220 0.5% 1/10W (NC615) R409 1-218-831-11 METAL CHIP 220 0.5% 1/10W (NC615) R410 1-218-831-11 METAL CHIP 220 0.5% 1/10W (NC615) R411 1-218-831-11 METAL CHIP 220 0.5% 1/10W (NC615) R412 1-216-833-11 METAL CHIP 10K 5% 1/10W R413 1-218-867-11 RES-CHIP 6.8K 5% 1/10W R414 1-216-822-11 METAL CHIP 1.2K 5% 1/10W R415 1-216-797-11 METAL CHIP 10 5% 1/10W (NC655P) R423 1-216-833-11 METAL CHIP 10K 5% 1/10W R426 1-216-833-11 METAL CHIP 10K 5% 1/10W R430 1-216-797-11 METAL CHIP 10 5% 1/10W R436 1-216-864-11 METAL CHIP 0 (NC655P) R438 1-216-864-11 METAL CHIP 0 (NC655P) R439 1-216-864-11 METAL CHIP 0 R507 1-216-809-11 METAL CHIP 100 5% 1/10W (NC655P) R511 1-216-809-11 METAL CHIP 100 5% 1/10W (NC655P) R512 1-216-864-11 METAL CHIP 0 (NC655P) R513 1-218-285-11 RES-CHIP 75 5% 1/10W (NC655P) R514 1-218-292-11 RES-CHIP 20K 5% 1/10W (NC655P) R536 1-216-809-11 METAL CHIP 100 5% 1/10W (NC655P) R558 1-216-809-11 METAL CHIP 100 5% 1/10W (NC655P) R559 1-216-809-11 METAL CHIP 100 5% 1/10W (NC655P) R568 1-216-819-11 METAL CHIP 680 5% 1/10W (NC655P) R570 1-216-822-11 METAL CHIP 1.2K 5% 1/10W (NC655P) R571 1-216-822-11 METAL CHIP 1.2K 5% 1/10W (NC655P) R573 1-216-809-11 METAL CHIP 100 5% 1/10W (NC655P) R574 1-218-834-11 METAL CHIP 300 0.5% 1/10W (NC655P) R575 1-218-834-11 METAL CHIP 300 0.5% 1/10W (NC655P) R576 1-218-834-11 METAL CHIP 300 0.5% 1/10W (NC655P) R577 1-218-834-11 METAL CHIP 300 0.5% 1/10W (NC655P) R578 1-218-834-11 METAL CHIP 300 0.5% 1/10W (NC655P) MB-103 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 8-16E Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks PL-31 R579 1-218-834-11 METAL CHIP 300 0.5% 1/10W (NC655P) R585 1-216-833-11 METAL CHIP 10K 5% 1/10W (NC655P) R601 1-216-809-11 METAL CHIP 100 5% 1/10W R607 1-216-864-11 METAL CHIP 0 (NC615) R608 1-216-864-11 METAL CHIP 0 (NC615) R609 1-216-864-11 METAL CHIP 0 (NC615) R612 1-216-864-11 METAL CHIP 0 (NC615) R613 1-216-864-11 METAL CHIP 0 (NC655P) R614 1-216-864-11 METAL CHIP 0 (NC655P) R619 1-216-864-11 METAL CHIP 0 (NC655P) R621 1-216-864-11 METAL CHIP 0 (NC615:AEP,UK,AUS,SP) < COMPOSITION CIRCUIT BLOCK > * RB102 1-233-270-11 NETWORK, RES (8 GANG) 10K < VARIABLE RESISTOR > RV401 1-223-583-11 RES, ADJ, CARBON 1K (NC615) RV501 1-223-583-11 RES, ADJ, CARBON 1K (NC655P) RV502 1-223-583-11 RES, ADJ, CARBON 1K (NC655P) < VIBRATOR > X101 1-795-174-11 VIBRATOR, CERAMIC (16.5MHz) X102 1-781-867-21 VIBRATOR, CRYSTAL (27MHz) ************************************************************ MD-94 BOARD, COMPLETE ********************** < CONNECTOR > CN001 1-506-490-21 PIN, CONNECTOR 11P CN002 1-784-767-11 CONNECTOR, FFC 6P * CN003 1-564-013-11 PIN, CONNECTOR 3P CN004 1-506-481-11 PIN, CONNECTOR 2P ************************************************************ PL-31 (X) COMPL (NC655P) *********************** < CONNECTOR > CN601 1-564-002-11 PIN, CONNECTOR 3P < DIODE > D601 8-719-056-06 DIODE SLR-342DCT31 < RESISTOR > R601 1-216-021-00 METAL CHIP 68 5% 1/10W ************************************************************ SE-130 BOARD, COMPLETE ********************** < CONNECTOR > CN101 1-750-243-11 SOCKET, CONNECTOR 6P CN102 1-573-383-11 PIN, CONNECTOR (PC BOARD) 2P 8-749-017-45 SENSOR, PHONT RPR-220C1N ************************************************************ 0 1-468-641-11 POWER BLOCK (HS10S1U) (NC615:US,CND/NC655P) ************************************** < FUSE > 0F101 1-533-296-11 FUSE 2A/125V ************************************************************ 0 1-468-642-11 POWER BLOCK (HS10S1F) (NC615:PX,E,AEP,UK,AUS,SP) ************************************** < FUSE > 0F101 1-532-503-31 FUSE 2A/250V ************************************************************ MISCELLANEOUS ************** 02 1-468-641-11 POWER BLOCK (NC615:US,CND/NC655P) 02 1-468-642-11 POWER BLOCK (NC615:PX,E,AEP,UK,AUS,SP) 08 1-575-651-21 CORD, POWER (NC615:PX,E,AEP,UK,SP) 08 1-783-531-31 CORD, POWER (NC615:US,CND/NC655P) 08 1-790-588-11 CORD, POWER (NC615:AUS) 52 1-786-131-11 SWITCH, TACTILE (NC655P) ************************************************************ ACCESSORIES ************ 1-477-126-11 REMOTE COMMANDER (RMT-D143A) (NC615:US,CND,PX,E) 1-477-126-21 REMOTE COMMANDER (RMT-D143P) (NC615:AEP,UK) 1-477-126-31 REMOTE COMMANDER (RMT-D143E) (NC615:AUS,SP) 1-477-127-11 REMOTE COMMANDER (RMT-D144A)(NC655P) 1-569-008-21 ADAPTOR, CONVERSION 2P (NC615:PX,E) 1-751-271-11 CORD, CONNECTION 1-770-019-12 ADAPTOR, CONVERSION PLUG 3P (NC615:UK) 1-823-364-21 CORD, CONNECTION (AV CABLE) (1.5m) 3-072-138-01 COVER (SANWA), BATTERY (FOR RMT-D143A/D143P/D143E)(NC615) 3-073-096-01 COVER (SANWA), BATTERY (FOR RMT-D144A) (NC655P) 3-074-252-11 MANUAL, INSTRUCTION (ENGLISH) (NC615:US,CND,PX,AUS,SP) 3-074-252-21 MANUAL, INSTRUCTION (FRENCH) (NC615:CND) 3-074-252-31 MANUAL, INSTRUCTION (SPANISH)(NC615:E) 3-074-252-41 MANUAL, INSTRUCTION (ENGLISH) (NC615:UK) 3-074-252-51 MANUAL, INSTRUCTION (FRENCH) (NC615:AEP) 3-074-252-61 MANUAL, INSTRUCTION (GERMAN) (NC615:AEP) 3-074-252-71 MANUAL, INSTRUCTION (ITALIAN)(NC615:AEP) 3-074-252-81 MANUAL, INSTRUCTION (DUTCH)(NC615:AEP) 3-074-252-91 MANUAL, INSTRUCTION (SPANISH) (NC615:AEP) 3-074-253-11 MANUAL, INSTRUCTION (ENGLISH)(NC655P) 3-074-288-11 MANUAL, INSTRUCTION (SIMPLIFIED CHINESE)(NC615:SP) Note : The components identified by mark 0 or dotted line with mark 0 are critical for safety. Replace only with part number specified. Note : Les composants identifiés par une marque 0 sont critiques pour la sécurité. Ne les remplacer que par une pièce portant le numéro spécifié. MB-103 MD-94 SE-130 POWER (HS10S1F) POWER (HS10S1U) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DVP-NC615/NC655P — 168 — Sony Corporation Home Video Company 9-929-724-11 2002E1600-1 ©2002.5 Published by Quality Assurance Dept. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com
