SERVICE MANUAL CD/DVD PLAYER US Model Canadian Model DVP-CX995V Ver. 1.1 2005.12 SPECIFICATIONS 9-879-772-02 2005L05-1 © 2005.12 Sony Corporation Home Audio Division Published by Sony Engineering Corporation Model Name Using Similar Mechanism NEW CD/DVD Mechanism Type CDM62-DVBU65 Base Unit Name DVBU65 Optical Traverse Unit Name DBU-3 * Manufactured under license from Dolby Laboratories. “Dolby,” “Pro Logic,” and the double-D symbol are trademarks of Dolby Laboratories. ** “DTS” and “DTS Digital Surround” are registered trademarks of Digital Theater Systems, Inc. System Laser: Semiconductor laser λ = 780 nm for CD λ = 650 nm for Super Audio CD and DVD Emission duration: continuous Signal format system: NTSC Audio characteristics Frequency response: DVD VIDEO (PCM 96 kHz): 2 Hz to 44 kHz (44 kHz: –2 dB ±1 dB), Super Audio CD: 2 Hz to 100 kHz (50 kHz: –3 dB ±1 dB), CD: 2 Hz to 20 kHz (±0.5 dB) Signal-to-noise ratio (S/N ratio): 115 dB (LINE OUT AUDIO L/R 1/2 jacks only) Harmonic distortion: 0.003 % Dynamic range: DVD VIDEO/Super Audio CD: 103 dB, CD: 99 dB Wow and flutter: Less than detected value (±0.001% W PEAK) Outputs (Jack name: Jack type/Output level/Load impedance) LINE OUT AUDIO L/R 1/2: Phono jack/ 2 Vrms/10 kilohms DIGITAL OUT (OPTICAL): Optical output jack/–18 dBm (wave length: 660 nm) DIGITAL OUT (COAXIAL): Phono jack/ 0.5 Vp-p/75 ohms HDMI OUTPUT: TypeA (19 pin) 5.1CH OUTPUT: Phono jack/2 Vrms/ 10 kilohms COMPONENT VIDEO OUT(Y, PB/CB, PR/ CR): Phono jack/Y: 1.0 Vp-p/PB/CB, PR/CR: interlace1) = 0.648 Vp-p, progressive or interlace2) = 0.7 Vp-p/75 ohms 1) BLACK LEVEL (COMPONENT OUT) is ON 2) BLACK LEVEL (COMPONENT OUT) is OFF LINE OUT (VIDEO) 1/2: Phono jack/ 1.0 Vp-p/75 ohms S VIDEO OUT 1/2: 4-pin mini DIN/Y: 1.0 Vp-p, C: 0.286 Vp-p/75 ohms General Power requirements: 120 V AC, 60 Hz Power consumption: 25 W Dimensions (approx.): 430 × 189 × 545 mm (17 × 7 1/2 × 211/2 in.) (width/height/depth) incl. projecting parts Mass (approx.): 8.6 kg (18 lb 15 oz) Operating temperature: 5 °C to 35 °C (41 °F to 95 °F) Operating humidity: 25 % to 80 % Supplied accessories • Audio/video cord (pinplug × 3 y pinplug × 3) (1) Specifications and design are subject to change without notice. • Remote commander (remote) (1) • Size AA (R6) batteries (2) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 2 DVP-CX995V Notes on chip component replacement • Never reuse a disconnected chip component. • Notice that the minus side of a tantalum capacitor may be damaged by heat. Flexible Circuit Board Repairing • Keep the temperature of the soldering iron around 270 ˚C during repairing. • Do not touch the soldering iron on the same conductor of the circuit board (within 3 times). • Be careful not to apply force on the conductor when soldering or unsoldering. CAUTION Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure. UNLEADED SOLDER Boards requiring use of unleaded solder are printed with the lead- free mark (LF) indicating the solder contains no lead. (Caution: Some printed circuit boards may not come printed with the lead free mark due to their particular size) : LEAD FREE MARK Unleaded solder has the following characteristics. • Unleaded solder melts at a temperature about 40 ˚C higher than ordinary solder. Ordinary soldering irons can be used but the iron tip has to be applied to the solder joint for a slightly longer time. Soldering irons using a temperature regulator should be set to about 350 ˚C. Caution: The printed pattern (copper foil) may peel away if the heated tip is applied for too long, so be careful! • Strong viscosity Unleaded solder is more viscou-s (sticky, less prone to flow) than ordinary solder so use caution not to let solder bridges occur such as on IC pins, etc. • Usable with ordinary solder It is best to use only unleaded solder but unleaded solder may also be added to ordinary solder. SAFETY-RELATED COMPONENT WARNING!! COMPONENTS IDENTIFIED BY MARK 0 OR DOTTED LINE WITH MARK 0 ON THE SCHEMATIC DIAGRAMS AND IN THE PARTS LIST ARE CRITICAL TO SAFE OPERATION. REPLACE THESE COMPONENTS WITH SONY PARTS WHOSE PART NUMBERS APPEAR AS SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUBLISHED BY SONY. SAFETY CHECK-OUT After correcting the original service problem, perform the following safety check before releasing the set to the customer: Check the antenna terminals, metal trim, “metallized” knobs, screws, and all other exposed metal parts for AC leakage. Check leakage as described below. LEAKAGE TEST The AC leakage from any exposed metal part to earth ground and from all exposed metal parts to any exposed metal part having a return to chassis, must not exceed 0.5 mA (500 microamperes.). Leakage current can be measured by any one of three methods. 1. A commercial leakage tester, such as the Simpson 229 or RCA WT-540A. Follow the manufacturers’ instructions to use these instruments. 2. A battery-operated AC milliammeter. The Data Precision 245 digital multimeter is suitable for this job. 3. Measuring the voltage drop across a resistor by means of a VOM or battery-operated AC voltmeter. The “limit” indication is 0.75 V, so analog meters must have an accurate low-voltage scale. The Simpson 250 and Sanwa SH-63Trd are examples of a passive VOM that is suitable. Nearly all battery operated digital multimeters that have a 2 V AC range are suitable. (See Fig. A) Fig. A. Using an AC voltmeter to check AC leakage. 1.5 kΩ 0.15 µF AC voltmeter (0.75 V) To Exposed Metal Parts on Set Earth Ground ATTENTION AU COMPOSANT AYANT RAPPORT À LA SÉCURITÉ! LES COMPOSANTS IDENTIFIÉS PAR UNE MARQUE 0 SUR LES DIAGRAMMES SCHÉMATIQUES ET LA LISTE DES PIÈCES SONT CRITIQUES POUR LA SÉCURITÉ DE FONCTIONNEMENT. NE REMPLACER CES COM- POSANTS QUE PAR DES PIÈCES SONY DONT LES NUMÉROS SONT DONNÉS DANS CE MANUEL OU DANS LES SUPPLÉMENTS PUBLIÉS PAR SONY. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 3 DVP-CX995V TABLE OF CONTENTS 1. SERVICING NOTES ............................................... 4 2. GENERAL ................................................................... 9 3. DISASSEMBLY 3-1. Disassembly Flow ........................................................... 10 3-2. Case ................................................................................. 11 3-3. MB Board ........................................................................ 11 3-4. AV Board ......................................................................... 12 3-5. Bracket (L)/(R) ................................................................ 12 3-6. Front Panel Section ......................................................... 13 3-7. Cover (PT)/(CDM) .......................................................... 13 3-8. DVBU65 Assy ................................................................. 14 3-9. Switching Regulator ........................................................ 14 3-10. Table (400) Assy .............................................................. 15 3-11. Door Assy, Base (Door) Assy .......................................... 15 3-12. DC Motor (Door) (M603) ............................................... 16 3-13. Holder (Table Sensor 400)............................................... 16 3-14. D. SENS OUT Board, D. SENS IN Board ...................... 17 3-15. Pop-up (400) Assy ........................................................... 17 3-16. DOOR SW Board ............................................................ 18 3-17. LOCK SW Board, LOADING SW Board ...................... 19 3-18. CD/DVD Mechanism Deck Block (CDM62-DVBU65) ......................................................... 20 3-19. Motor (400) Assy (Loading) (M602)/(Table) (M601), LOADING MOTOR Board ............................................. 20 3-20. Optical Traverse Unit (DBU-3) ....................................... 21 4. TEST MODE .............................................................. 22 5. MECHANICAL ADJUSTMENTS ....................... 32 6. ELECTRICAL ADJUSTMENTS ......................... 33 7. DIAGRAMS 7-1. Block Diagram – SERVO Section – ................................ 38 7-2. Block Diagram – AUDIO Section – ................................ 39 7-3. Block Diagram – VIDEO Section – ................................ 40 7-4. Block Diagram – PANEL, TABLE, POWER SUPPLY Section – ............ 41 7-5. Printed Wiring Board – RF TRANSLATION Board – ... 43 7-6. Printed Wiring Board – MB Board (Side A) – ................ 44 7-7. Printed Wiring Board – MB Board (Side B) – ................ 45 7-8. Schematic Diagram – MB Section (1/7) – ...................... 46 7-9. Schematic Diagram – MB Section (2/7) – ...................... 47 7-10. Schematic Diagram – MB Section (3/7) – ...................... 48 7-11. Schematic Diagram – MB Section (4/7) – ...................... 49 7-12. Schematic Diagram – MB Section (5/7) – ...................... 50 7-13. Schematic Diagram – MB Section (6/7) – ...................... 51 7-14. Schematic Diagram – MB Section (7/7) – ...................... 52 7-15. Schematic Diagram – AV Board (1/5) – .......................... 53 7-16. Schematic Diagram – AV Board (2/5) – .......................... 54 7-17. Schematic Diagram – AV Board (3/5) – .......................... 55 7-18. Schematic Diagram – AV Board (4/5) – .......................... 56 7-19. Schematic Diagram – AV Board (5/5) – .......................... 57 7-20. Printed Wiring Board – AV Board (Component Side) – ..................................... 58 7-21. Printed Wiring Board – AV Board (Conductor Side) –....................................... 59 7-22. Printed Wiring Boards – TABLE Section –..................... 60 7-23. Schematic Diagram – TABLE Section – ......................... 61 7-24. Printed Wiring Board – DRIVER Board – ...................... 62 7-25. Schematic Diagram – DRIVER Board – ......................... 63 7-26. Printed Wiring Board – PANEL-L Board –..................... 64 7-27. Schematic Diagram – PANEL-L Board – ....................... 65 7-28. Printed Wiring Boards – PANEL-R Section –................. 66 7-29. Schematic Diagram – PANEL-R Section – ..................... 67 8. EXPLODED VIEWS 8-1. Overall Section ................................................................ 90 8-2. Front Panel Section ......................................................... 91 8-3. Power Block Section ....................................................... 92 8-4. Table Section ................................................................... 93 8-5. Chassis Section ................................................................ 94 8-6. Base (Door) Section ........................................................ 95 8-7. CD/DVD Mechanism Deck Section-1 (Pop-up Block) ................................................................ 96 8-8. CD/DVD Mechanism Deck Section-2 (Pulley Block).................................................................. 97 8-9. CD/DVD Mechanism Deck Section-3 (Lever, Holder Block)...................................................... 98 8-10. CD/DVD Mechanism Deck Section-4 (Gear, Motor Block) ........................................................ 99 8-11. Base Unit Section (DVBU65) ........................................ 100 9. ELECTRICAL PARTS LIST ............................... 101 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 4 DVP-CX995V SECTION 1 SERVICING NOTES The laser diode in the optical pick-up block may suffer electrostatic break-down because of the potential difference generated by the charged electrostatic load, etc. on clothing and the human body. During repair, pay attention to electrostatic break-down and also use the procedure in the printed matter which is included in the repair parts. The flexible board is easily damaged and should be handled with care. NOTES ON LASER DIODE EMISSION CHECK The laser beam on this model is concentrated so as to be focused on the disc reflective surface by the objective lens in the optical pick- up block. Therefore, when checking the laser diode emission, observe from more than 30 cm away from the objective lens. NOTES ON REPLACEMENT OF THE MB BOARD 1. Flash Memory New part of flash memory (IC202) on the MB board cannot be used. Therefore, if the mounted MB board (A-1132-163-A) is replaced, exchange new flash memory with that used before the replacement. 2. Adjustment When replacing the mounted MB board (A-1132-163-A), since the adjustment value is not set up correctly, “Drive Auto Adjustment” in the Test Mode can’t be performed. In this case, initialize memory in the following procedures. Procedure: 1. Connect a video monitor to VIDEO LINE OUT jack (J103). 2. Press the [TOP MENU], [CLEAR], I/1 keys on the remote commander (RM-ASP001) in this order with standby status to enter the Test Mode, then “DIAG START” will be displayed on the fluorescent indicator tube and the Test Mode Menu screen will be displayed on the video monitor. 3. Press the [2] key on the remote commander to select the “2. Drive Manual Operation”. 4. Press the [6] key on the remote commander to select the “6. Memory Check”. 5. Press the [CLEAR] key on the remote commander to initialize the memory. Note: Refer to page 22 for detail of the Test Mode. NOTES ON HANDLING THE OPTICAL PICK-UP BLOCK OR BASE UNIT Ver. 1.1 NOTE OF HANDLING THE AV BOARD (Part No. A- 1126-999-A) When the AV board is replaced by a repair for a fee, throw away the AV board after obtaining consent of not returning of the AV board to the customer. When throwing away the AV board, be sure to throw away after destroying IC600 physically with the hammer etc. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 5 DVP-CX995V This Player Can Play the Following Discs “DVD VIDEO” and “DVD-RW” are trademarks. Note about CDs The player can play CD-ROMs/CD-Rs/CD- RWs recorded in the following formats: – music CD format – video CD format – MP3 audio tracks and JPEG image files of format conforming to ISO 9660* Level 1/ Level 2, or its extended format, Joliet – KODAK Picture CD format * A logical format of files and folders on CD- ROMs, defined by ISO (International Organization for Standardization). Format of discs Attention Regarding DualDisc software This product has been engineered to provide the highest entertainment value while playing standard CD and DVD discs. DualDisc used with this product may jam in the slots or racks of disc holders or in the disc consoles and should not be used with this product. DVD VIDEO DVD-RW Super Audio CD VIDEO CD Music CD Region code Your player has a region code printed on the back of the unit and will only play DVD VIDEOs (playback only) labeled with identical region codes. This system is used to protect copyrights. DVD VIDEOs labeled will also play on this player. If you try to play any other DVD VIDEO, the message “Playback prohibited by area limitations.” will appear on the TV screen. Depending on the DVD VIDEO, no region code indication may be labeled even though playing the DVD VIDEO is prohibited by area restrictions. Example of discs that the player cannot play The player cannot play the following discs: • CD-ROMs/CD-Rs/CD-RWs other than those recorded in the format listed on the previous page. • Data part of CD-Extras • DVD-ROMs • DVD Audios Also, the player cannot play the following discs: • A DVD VIDEO with a different region code. • A disc recorded in a color system other than NTSC, such as PAL or SECAM (this player conforms to the NTSC color system). • A disc that has a non-standard shape (e.g., card, heart). • A disc with paper or stickers on it. • A disc that has the adhesive of cellophane tape or a sticker still left on it. • DVD-Rs recorded in VR mode (Video Recording format) • Copy-Once programs recorded on CPRM* compatible DVD-Rs. • An 8 cm disc (The 12 cm disc adapter should not be used for 8 cm discs because it may cause the disc to jam or the player to malfunction). * CPRM; Content Protection for Recordable Media is a coding technology that protects copyright for Copy-Once programs. Notes • Notes about DVD+RWs/DVD+Rs, DVD-RWs/ DVD-Rs or CD-Rs/CD-RWs Some DVD+RWs/DVD+Rs, DVD-RWs/DVD- Rs or CD-Rs/CD-RWs cannot be played on this player due to the recording quality or physical condition of the disc, or the characteristics of the recording device and authoring software. The disc will not play if it has not been correctly finalized. For more information, see the operating instructions for the recording device. Note that some playback functions may not work with some DVD+RWs/DVD+Rs, even if they have been correctly finalized. In this case, view the disc by normal playback. Also some DATA CDs created in Packet Write format cannot be played. • Music discs encoded with copyright protection technologies This product is designed to playback discs that conform to the Compact Disc (CD) standard. Recently, various music discs encoded with copyright protection technologies are marketed by some record companies. Please be aware that among those discs, there are some that do not conform to the CD standard and may not be playable by this product. Note on playback operations of DVDs and VIDEO CDs Some playback operations of DVDs and VIDEO CDs may be intentionally set by software producers. Since this player plays DVDs and VIDEO CDs according to the disc contents the software producers designed, some playback features may not be available. Also, refer to the instructions supplied with the DVDs or VIDEO CDs. Copyrights This product incorporates copyright protection technology that is protected by U.S. patents and other intellectual property rights. Use of this copyright protection technology must be authorized by Macrovision, and is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision. Reverse engineering or disassembly is prohibited. ALL Region code www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 6 DVP-CX995V AV board AV board – Front side – MB board cables (MB board to DRIVER board, SENSOR board) cables (MB board to DRIVER board, SENSOR board) MB board AV board switching regulator locking wire saddle MB board It takes care that the cables doesn’t hang down. cable (AV board to PANEL-L board) cables (MB board to DRIVER board, SENSOR board) cable (MB board to LED board) ALIGNMENT OF GEAR (CAM) PHASE WITH DOOR ASS’Y CLEANING OF OPTICAL PICK-UP door assy gear (cam) Align a slit of door assy with a marking on the bottom land of gear tooth when the gear is rotated fully in arrow direction, as shown. optical pick-up pulley assy Remove the pulley assy, and clean the lens of optical pick-up through this hole. NOTE FOR INSTALLATION www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 7 DVP-CX995V DRIVER board cables cables When installing the cables, it is made to make it crawl in a chassis. AV board AV board cables It is made to contact and for there not to be a switching regulator and cables. switching regulator MB board switching regulator www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 8 DVP-CX995V SERVICE POSITION – MB board – – Optical pick-up block – MB board (CN303) Connect the jig (J-2501-199-A) to MB board (CN303) and PANEL-L board (CN1003). PANEL-L board (CN1003) optical pick-up block (DVBU65) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 9 DVP-CX995V SECTION 2 GENERAL This section is extracted from instruction manual. • Location of Controls Front panel A [/1 (on/standby) button B HDMI* (High-Definition Multimedia Interface) indicator Lights up when the HDMI OUT jack is correctly connected to a HDCP (High- bandwidth Digital Content Protection) compliant device with HDMI or DVI (Digital Visual Interface) input. C SA-CD (Super Audio CD) indicator Lights up when: — playing a Super Audio CD. — a Super Audio CD (Hybrid disc) is inserted. D MULTI CHANNEL indicator Lights up when playing a track or chapter that contains three or more audio signal channels. E Front panel display F Front cover G OPEN/CLOSE button H A DISC EJECT button I H (play) button J X (pause) button K x (stop) button L +100 button M DISC CHANGE button/indicator N DIRECT SEARCH button/indicator O .–/>+/ENTER (previous/next/ enter) dial P DISPLAY button Q C/X/x/c/ENTER buttons R O RETURN button S TOP MENU button T MENU button U PICTURE MODE button V REPEAT button W ONE/ALL DISCS button X FOLDER button Y LOAD button Z (remote sensor) wj KEYBOARD jack wk FL OFF button/indicator wl TIME/TEXT button * This player is based on version 1.1 of High- Definition Multimedia Interface Specifications. This DVD player incorporates High-Definition Multimedia Interface (HDMI™) technology. HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC. Front panel display When playing back a DVD VIDEO/DVD-RW When playing back a VIDEO CD with Playback Control (PBC) When playing back a CD, Super Audio CD, DATA CD (MP3 audio), or VIDEO CD (without PBC) Playing time Disc type Current audio signal Lights up when you can change the angle Current play mode Playing status Current title and chapter Current disc All discs mode Lights up when the player outputs progressive signals Disc type Playing time Playing status Current play mode All discs mode Current disc Current scene Playing time Disc type Current track (CD, Super Audio CD, VIDEO CD) or album (DATA CD) Lights up when playing MP3 audio tracks* Playing status Current disc Current play mode All discs mode Current index (CD, Super Audio CD, VIDEO CD) or track (DATA CD) * When playing JPEG image files, “JPEG” appears on the display To turn off the front panel display Press FL OFF on the player. The front panel display turns off, and the FL OFF indicator on the player lights up. z Hint You can adjust the lighting of the front panel display by setting “DIMMER” in “CUSTOM SETUP”. Rear panel A DIGITAL OUT (COAXIAL) jack B DIGITAL OUT (OPTICAL) jack C 5.1CH OUTPUT jacks D LINE OUT AUDIO L/R 1/2 jacks E LINE OUT VIDEO 1/2 jacks F S VIDEO OUT 1/2 jacks G COMPONENT VIDEO OUT (Y, PB/ CB, PR/CR) jacks H HDMI OUT (high-definition multimedia interface out) jack Remote A TV/DISC EXPLORER/DVD switch B OPEN/CLOSE button C Number buttons The number 5 button has a tactile dot.* D CLEAR button E TOP MENU/EDIT button L ZOOM button M SA-CD MULTI/2CH (Super Audio CD multi/2 channel) button N SA-CD/CD (Super Audio CD/CD) button O TIME/TEXT button P REPEAT button Q AUDIO button R SUBTITLE button S [/1 (on/standby) button T VOL (volume) +/– buttons The + button has a tactile dot.* U TV/VIDEO/DISC SKIP + button V ENTER/FOLDER button W WIDE MODE/DISC SKIP – button X MENU/SORT button Y ENTER button Z DISPLAY/FILE button wj C STEP/ADVANCE button wk > NEXT (next) buttons wl M SCAN/SLOW buttons e; x STOP button ea X PAUSE button es PICTURE MEMORY button ed PICTURE NAVI (picture navigation) button ef ALBUM +/– buttons eg PICTURE MODE button eh ANGLE button * Use the tactile dot as a reference when operating the player. F C/X/x/c buttons G O RETURN button H c STEP/REPLAY button I . PREV (previous) buttons J m SCAN/SLOW buttons K H PLAY button The H button has a tactile dot.* www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DVP-CX995V 10 SECTION 3 DISASSEMBLY • This set can be disassembled in the order shown below. 3-1. DISASSEMBLY FLOW Set 3-2. CASE (Page 11) 3-3. MB BOARD (Page 11) 3-4. AV BOARD (Page 12) 3-5. BRACKET (L)/(R) (Page 12) 3-6. FRONT PANEL SECTION (Page 13) 3-7. COVER (PT)/(CDM) (Page 13) 3-8. DVBU65 ASSY (Page 14) 3-9. SWITCHING REGULATOR (Page 14) 3-10. TABLE (400) ASSY (Page 15) 3-11. DOOR ASSY, BASE (DOOR) ASSY (Page 15) 3-12. DC MOTOR (DOOR) (M603) (Page 16) 3-13. HOLDER (TABLE SENSOR 400) (Page 16) 3-14. D. SENS OUT BOARD, D. SENS IN BOARD (Page 17) 3-15. POP-UP (400) ASSY (Page 17) 3-16. DOOR SW BOARD (Page 18) 3-17. LOCK SW BOARD, LOADING SW BOARD (Page 19) 3-18. CD/DVD MECHANISM DECK BLOCK (CDM62-DVBU65) (Page 20) 3-19. MOTOR (400) ASSY (LOADING) (M602)/(TABLE) (M601), LOADING MOTOR BOARD (Page 20) 3-20. OPTICAL TRAVERSE UNIT (DBU-3) (Page 21) Note 1: The process described in can be performed in any order. Note 2: Without completing the process described in , the next process can not be performed. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DVP-CX995V 11 Note: Follow the disassembly procedure in the numerical order given. 3-2. CASE 3-3. MB BOARD 3 three screws (case 3 TP2) 2 two screws (case 3 TP2) 5 case 4 two screws (case 3 TP2) 1 two screws (case 3 TP2) qs MB board 8 two screws (BVTP3 × 8) 9 two harnesses 1 wire (flat type) (25 core) (CN303) 7 connector (CN304) 6 connector (CN305) 2 flat type wire (31 core) (CN101) 5 flat type wire (29 core) (CN501) 4 flat type wire (33 core) (CN205) 3 tape 0 two screws (BVTP3 × 8) qa connector (CN203) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DVP-CX995V 12 4 screw (BVTP3 × 8) 8 flat type wire (33 core) (CN400) 9 flat type wire (29 core) (CN306) 1 flat type wire (31 core) (CN101) 7 2 eight screws (BVTP3 × 8) 3 screw (BVTT3 × 8) 0 connector (CN304) qa connector (CN303) qs connector (CN302) qd connector (CN301) qf AV board 6 harness 5 screw (BV3) 3-4. AV BOARD 3-5. BRACKET (L)/(R) 4 screw (BVTP3 × 8) 3 two screws (BVTP3 × 8) 1 two screws (BVTP3 × 8) 5 bracket (R) 2 bracket (L) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DVP-CX995V 13 3-6. FRONT PANEL SECTION 3-7. COVER (PT)/(CDM) 6 front panel section 1 five screws (BVTP3 × 8) 3 two screws (BVTP3 × 8) 2 screw (BVTP3 × 8) 5 claw 4 claw 1 screw (BVTP3 × 8) 3 cover (PT) 2 screw (BVTP3 × 8) 8 three screws (BVTP3 × 8) 4 six screws (BVTP3 × 8) 5 three screws (BVTP3 × 8) 6 cover (CDM) 7 bracket (shield) double-faced tape 9 bracket (CDM) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DVP-CX995V 14 3 two screws (BVTP3 × 8) 1 three screws (BVTP3 × 8) 5 bracket (top 400) block 6 torsion holder (magnet) block 8 torsion spring (MG) 7 washer 0 8 washer 2 screw (BVTP3 × 8) 9 DVBU65 assy 4 screw (BVTP3 × 8) 3-8. DVBU65 ASSY 3-9. SWITCHING REGULATOR Note: When installing the rear panel, tighten three screws first in following the order. 1 screw (BVTP3 × 8) 3 rear panel block 7 switching regulator 6 two screws (BVTP3 × 8) 4 connector (CN101) 5 screw (BVTP3 × 8) 2 two screws (BVTP3 × 8) rear panel 1 2 3 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DVP-CX995V 15 3-10. TABLE (400) ASSY 3-11. DOOR ASSY, BASE (DOOR) ASSY 1 screw (M3 × 14) 2 guide (door) 3 table (400) assy 4 10 washer Note: When installing the guide (door), align the positions as shown. 2 three screws (BVTP3 × 8) 1 connector (CN904) 3 cover (table) 4 door assy 5 two screws (BVTP3 × 8) 6 eight screws (BVTP3 × 8) 7 base (door) assy www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DVP-CX995V 16 3-12. DC MOTOR (DOOR) (M603) 3-13. HOLDER (TABLE SENSOR 400) 1 belt (400) 4 DOOR MOTOR board 5 DC motor (door) (M603) 3 Remove two solders. 2 two screws (BVTP3 × 8) 1 four screws (BVTP3 × 6) 4 SENSOR board 5 screw (PTTWH3 × 6) 2 connector (CN83) 3 two connectors (CN81, CN82) 6 two claws 7 holder (table sensor 400) 6 claw www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DVP-CX995V 17 3-14. D. SENS OUT BOARD, D. SENS IN BOARD 3-15. POP-UP (400) ASSY 5 screw (PSW3 × 8) 6 D. SENS OUT board 1 screw (PTTWH3 × 6) 2 clamp 8 D. SENS IN board 3 two step screws (T1) 4 bracket (sensor 400) 7 screw (PSW3 × 8) 1 screw (PTPWH3 × 6) 2 step screw 3 pop-up (400) assy www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DVP-CX995V 18 3-16. DOOR SW BOARD 5 two screws (BVTP2.6) 3 screw (PTPWH2.6) 1 screw (PTPWH2.6) 1 Move the slider (pop-up) and the lever (pu joint) fully in the direction of the arrow A. 2 Install the gear (cam) in the direction shown in the illustration and rotate it fully in the direction of the arrow B. 3 When the gear (cam) happens to go too deep, return it to the original position in the direction of the arrow C. 4 gear (B) 2 gear (cam) 6 DOOR SW board C B A lever (pu joint) two rotary switches slider (pop-up) gear (cam) DOOR SW board The levers of the two rotary switches on the DOOR SW board are shown in the illustration below. Precaution during the gear (cam) installation www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DVP-CX995V 19 3-17. LOCK SW BOARD, LOADING SW BOARD claws 1 Rotate the pulley (400) in the direction of the arrow A fully. 3 Rotate the pulley (400) in the direction of the arrow B fully. 2 screw (BVTP3 × 8) 5 screw (BVTP3 × 12) 4 belt (400) 8 screw (BVTP3 × 8) 0 screw (BVTP2.6) qa LOADING SW board 9 LOCK SW board 7 gear (center) 6 pulley (400) Note for installation When installing the LOADING SW board and LOCK SW boards, align the leads position as shown. LOADING SW board LOCK SW board leads position A B www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DVP-CX995V 20 3-18. CD/DVD MECHANISM DECK BLOCK (CDM62-DVBU65) 3-19. MOTOR (400) ASSY (LOADING) (M602)/(TABLE) (M601), LOADING MOTOR BOARD 4 four screws (BVTP3 × 8) 3 screw (PSW3 × 8) 2 connector (CN903) 1 connector (CN905) 5 seven screws (BVTP3 × 8) 6 CD/DVD mechanism deck block (CDM62-DVBU65) 4 motor (400) assy (loading) (M602) 1 two belts (400) 3 Remove two solders. 5 Remove two solders. 2 three screws (BVTP3 × 8) 6 motor (400) assy (table) (M601) 7 LOADING MOTOR board www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DVP-CX995V 21 3-20. OPTICAL TRAVERSE UNIT (DBU-3) Note: After assembling the pick-up, remove the solder two points on RF TRANSLATION board. If the assembly and disassembly are not done incorrect sequence, the pick-up may be damaged. qd optical traverse unit (DBU-3) 8 step screw (M) qa insulator (RB) 9 step screw (M) qs insulator (RB) 3 flexible board (CN0029) 2 flat type wire (31 core) (CN003) 1 Make solder land two points short on RF TRANSLATION board for prevent damage by static electricity. DBU400 holder assy SL001 4 flexible flat cable (CN001) 5 screw (BVTP2.6) 6 RF TRANSLATION board 0 insulator (RB) 7 step screw (M) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 22 DVP-CX995V SECTION 4 TEST MODE DVD SECTION GENERAL DESCRIPTION The Test Mode allows you to make diagnosis and adjustment easily using the remote commander and monitor TV. The instructions, diagnostic results, etc. are given on the on-screen display (OSD). STARTING TEST MODE Press the [TOP MENU], [CLEAR], I/1 keys on the remote commander in this order with standby status, and the Test Mode starts, then “DIAG START” will be displayed on the fluorescent display tube and the menu shown below will be displayed on the TV screen. At the bottom of menu screen, the model name and revision number are displayed. Last Off at the lower right of screen indicates the information code concerning the last power off. To execute each function, select the desired menu and press its number on the remote commander. To exit from the Test Mode, press the I/1 key. Test Mode Menu 0. B/E Diagnosis 1. Drive Auto Adjustment 2. Drive Manual Operation 3. Mecha Aging 4. Emergency History 5. Version Information 6. Video Level Adjustment Exit: Power Key Model :DVP-CX995V Revision:x.xxx OPERATING THE SUB MENU 0. B/E Diagnosis The same contents as board detail check by serial interface can be checked from the remote commander. On the Test Mode Menu screen, press [0] key on the remote commander, and the following check menu will be displayed. ### BackEnd Diagnosis ### Check Menu 0 . Quit 1 . All 2 . Version 3 . Peripheral 4 . Servo 5 . Video 6 . Audio Model :DVP-CX995V Revision:x.xxx 0-0. Quit Quit the Syscon Diagnosis and return to the Test Mode Menu. 0-1. All (All items continuous check) This menu checks all diagnostic items continuously. Normally, all items are checked successively one after another automatically unless an error is found, but at a certain item that requires judgment through a visual check to the result, the following screen is displayed for the key entry. • Example display ### BackEnd Diagnosis ### 2. Version 2-0. Quit 2-1. ALL 2-2. Revision:x.xxx 2-5. Region:x Press NEXT Key to Continue Following the message, press > key to go to the next item. To quit the diagnosis and return to the Check Menu screen, press x or [ENTER] key. If an error occurred, the diagnosis is suspended. Press . key to repeat the same item where an error occurred, or > key to continue the check from the item next to faulty item. 0-2. Version (2-2) Revision ROM revision number is displayed. Error: Not detected. The revision number defined in the source file is displayed with four digits. (2-4) Model Type Model code is displayed. Error: Not detected. The model code read from the EEPROM is displayed with 2-digit hexadecimal number. (2-5) Region Region code is displayed. Error: Not detected. The region code determined from the model code is displayed. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 23 DVP-CX995V 0-3. Peripheral (3-2) Flash Rom Data delete t write t read, and accord check Error 32: Delete error Error 33: Write error Error 34: Read data discord Error may occur due to defect of access with the CPU (MB board IC205). (3-3) SA-CD Check Data write t read, and accord check Error 36: Write/read data discord Check for SA-CD circuit (MB board IC401 and around circuit). (3-4) Venc Check Register write t read, and accord check Error 37: Write/read data discord Error may occur due to defect of access with the CPU (MB board IC205). (3-7) PROV Check Data write t read, and accord check Error 39: Write/read data discord External RAM check for I/P converter (AV board IC401) too. (3-8) HDMI Check Register write t read, and accord check Error 43: Write/read data discord Error may occur due to defect of access with the HDMI transmitter (AV board IC600). 0-4. Servo (4-2) Servo (F/E) Check Data write t read, and accord check Error 41: Read data discord 0x9249, 0x2942 and 0x4294 are written to the RAM address 0x602 of the DVD interface (front-end) (MB board IC104) and then read for checking. 0-5. Video (5-2) Interlace Error: Not detected. The command is transferred to the video D/A converter (AV board IC500), and change the video signal to interlace. (5-3) Progressive AVD color bar command write t Video (Composite, Y/C) OUT Error: Not detected. The command is transferred to the video D/A converter (AV board IC500), and change the video signal to progressive. (5-4) Color Bar Error: Not detected. The command is transferred to the video D/A converter (AV board IC500), and the color bar signals are output from video terminals. 0-6. Audio Not used. 1. Drive Auto Adjustment DVD reference disc: Single Layer TDV-520CS0 (J-2501-236-A) (NTSC) HLX-503 (J-6090-069-A) (NTSC) HLX-504 (J-6090-088-A) (NTSC) Dual Layer TDV-540C (J-2501-235-A) (NTSC, Opposite) HLX-501 (J-6090-071-A) (NTSC) HLX-505 (J-6090-089-A) (NTSC) CD reference disc: LUV-P01 (4-999-032-01) YEDS-18 (3-702-101-01) PATD-012 (4-225-203-01) On the Test Mode Menu screen, press [1] key on the remote commander, and the drive auto adjustment menu will be displayed. ## Drive Auto Adjustment ## Adjustment Menu 0. ALL (DL:Parallel) 1. DVD-SL 2. CD 3. DVD-DL (Parallel) 4. ALL (DL:Opposite) 5. DVD-DL (Opposite) 9. CLEAR DATA Exit: RETURN Normally, [0] or [4] is selected to adjust DVD (single layer), CD, and DVD (dual layer) in this order. But, individual items can be adjusted for the case where adjustment is suspended due to an error. In this mode, the adjustment can be made easily through the operation following the message displayed on the screen. Which disc is currently adjusted is displayed on the fluorescent display tube. 1-0. ALL (DL: Parallel) Select [0] and press the [ENTER] key. Then, [1] DVD-SL disc, [2] CD disc, and [3] DVD-DL (Parallel) disc are adjusted in this order. Because the changer model can accept multiple discs in advance of adjustment, adjustments can be continued by exchanging discs automatically whenever an adjustment is completed following the instruction on screen. You can exit the adjustment by pressing the x button. In adjusting each disc, the mirror time is measured to check the disc type. In the auto adjustment, whether the disc type is correct is not checked unlike conventional models, and accordingly, take care not to insert a different type of disc. Three kinds of discs can be set in advance. In this case, set discs in order to the displayed number with following the massage. Every time after adjusting a disc, the disc is replaced and adjustment is continued automatically. Set Disc Disc slot number 1: DVD-SL (TDV-520CS0 or HLX-503 or HLX- 504) Disc slot number 2: CD (LUV-P01 or YEDS-18 or PATD-012) Disc slot number 3: DVD-DL (TDV-540C or HLX-501 or HLX- 505) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 24 DVP-CX995V 1-3. DVD Dual Layer Disc (Parallel) Select [3], insert DVD dual layer disc, and press [ENTER] key, and the adjustment will be made through the following steps, then adjusted values will be written to the flash memory. The disc slot No. 3 is used in the changer type model. If there is no disc on the disc slot No. 3, the tray will be open to wait for closing. If there is a disc on the table, the adjustment starts immediately. If you put a disc prior to adjustment, confirm that the DL disc is set on the disc slot 3. Also, when the adjustment is completed, the result of the each setting value is displayed as follows. DVD Dual Layer Disc Adjustment Steps 1. Sled Reset 2. Set Disc Type DL 3. Laser Diode (DVD) ON 4. Focus Error Check 5. Focus ON 6. Spindle Start 7. Tracking Error Level Adjust 8. Tracking Error Offset Adjust 9. Tracking ON 10. RF Level Adjustment 11. Spindle Calibration 12. Tracking Off 13. Tracking Error Level Adjust 2nd 14. Tracking Error Offset Adjust 2nd 15. Tracking ON 16. Auto Focus Gain Adjust L0 17. Auto Tacking Gain Adjust L0 18. Sled ON 19. CLV ON 1-1. DVD Single Layer Disc Select [1], insert DVD single layer disc, and press [ENTER] key, and the adjustment will be made through the following steps, then adjusted values will be written to the flash memory. The disc slot No. 1 is used in the changer type model. If there is no disc on the disc slot No. 1, the tray will be open to wait for closing. If there is a disc on the table, the adjustment starts immediately. If you put a disc prior to adjustment, confirm that the SL disc is set on the disc slot 1. Also, when the adjustment is completed, the result of the each setting value is displayed as follows. DVD Single Layer Disc Adjustment Steps 1. Sled Reset 2. Set Disc Type SL 3. Laser Diode (DVD) ON 4. Focus Error Check 5. Focus ON 6. Spindle Start 7. Tracking Error Level Adjust 8. Tracking Error Offset Adjust 9. Tracking ON 10. RF Level Adjustment 11. Spindle Calibration 12. Tracking Off 13. Tracking Error Level Adjust 2nd 14. Tracking Error Offset Adjust 2nd 15. Tracking ON 16. Auto Focus Gain Adjust L0 17. Auto Tracking Gain Adjust L0 18. Sled ON 19. CLV ON 20. Auto Focus Balance Adjust L0 21. Auto RFEQ Boost Adjust L0 22. Jitter measure 23. Search Check 24. All Servo Off Result Display Result disc type : SL An.Off.AB xx xx TE levDVD xx An.Off.CD xx xx TE levCD -- An.Off.EF -- -- TE Offset xx An.G.Main xx FCS Gain xx An.G.Side -- TRK Gain xx RF level xx FCS Bal. -- xx FE S L0,1 xx -- REFQ -- xx VTS2 xx Jitter xx Exit:RETURN 1-2. CD Disc Select [2], insert CD disc, and press [ENTER] key, and the adjustment will be made through the following steps, then adjusted values will be written to the flash memory. The disc slot No. 2 is used in the changer type model. If there is no disc on the disc slot No. 2, the tray will be open to wait for closing. If there is a disc on the table, the adjustment starts immediately. If you put a disc prior to adjustment, confirm that the CD is set on the disc slot 2. Also, when the adjustment is completed, the result of the each setting value is displayed as follows. CD Adjustment Steps 1. Sled Reset 2. Set Disc Type CD 3. Laser Diode (CD) ON 4. Focus Error Check 5. Focus ON 6. Spindle Start 7. Tracking Error Level Adjust 8. Tracking Error Offset Adjust 9. Tracking ON 10. RF Level Adjustment 11. Spindle Calibration 12. Auto Focus Gain Adjust 13. Auto Tracking Gain Adjust 14. Sled ON 15. CLV ON 16. Auto Focus Balance Adjust 17. Auto RFEQ Boost Adjust 18. Jitter measure 19. Search Check 20. All Servo Off Result Display Result disc type : CD An.Off.AB xx xx TE levDVD -- An.Off.CD xx xx TE levCD xx An.Off.EF xx xx TE Offset xx An.G.Main xx FCS Gain xx An.G.Side xx TRK Gain xx RF level xx FCS Bal. -- xx FE S L0,1 xx -- REFQ -- xx VTS2 -- Jitter xx Exit:RETURN www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 25 DVP-CX995V 20. Auto Focus Balance Adjust L0 21. Auto RFEQ Boost Adjust L0 22. Jitter measure 23. Search Check 24. Focus Jump (L0 t L1) 25. Tracking Off 26. Tracking Error Level Adjust 27. Tracking Error Offset Adjust 28. Tracking ON 29. Auto Focus Gain Adjust L1 30. Auto Tracking Gain Adjust L1 31. Sled ON 32. CLV ON 33. Auto Focus Balance Adjust L1 34. Auto RFEQ Boost Adjust L1 35. Search Check 36. All Servo Off Result Display Result disc type : DL L0 An.Off.AB xx xx TE levDVD xx An.Off.CD xx xx TE levCD -- An.Off.EF -- -- TE Offset xx An.G.Main xx FCS Gain xx An.G.Side -- TRK Gain xx RF level xx FCS Bal. -- xx FE S L0,1 xx -- REFQ -- xx VTS2 -- Jitter xx 1:L1 Page Exit:RETURN Result disc type : DL L1 An.Off.AB -- -- TE levDVD xx An.Off.CD -- -- TE levCD -- An.Off.EF -- -- TE Offset xx An.G.Main xx FCS Gain xx An.G.Side -- TRK Gain xx RF level xx FCS Bal. -- xx FE S L0,1 -- xx REFQ -- xx VTS2 -- Jitter -- 0:L0 Page Exit:RETURN 1-4. ALL (DL: Opposite) Select [4] and press the [ENTER] key. Then, [1] DVD-SL disc, [2] CD disc, and [5] DVD-DL (Opposite) disc are adjusted in this order. Because the changer model can accept multiple discs in advance of adjustment, adjustments can be continued by exchanging discs automatically whenever an adjustment is completed following the instruction on screen. You can exit the adjustment by pressing the x button. In adjusting each disc, the mirror time is measured to check the disc type. In the auto adjustment, whether the disc type is correct is not checked unlike conventional models, and accordingly, take care not to insert a different type of disc. Three kinds of discs can be set in advance. In this case, set discs in order to the displayed number with following the massage. Every time after adjusting a disc, the disc is replaced and adjustment is continued automatically. Set Disc Disc slot number 1: DVD-SL (TDV-520CS0 or HLX-503 or HLX- 504) Disc slot number 2: CD (LUV-P01 or YEDS-18 or PATD-012) Disc slot number 3: DVD-DL (TDV-540C only) 1-5. DVD Dual Layer Disc (Opposite) Note: Make sure, using the TDV-540C in this adjustment. Select [5], insert DVD dual layer disc, and press [ENTER] key, and the adjustment will be made through the following steps, then adjusted values will be written to the flash memory. The disc slot No. 3 is used in the changer type model. If there is no disc on the disc slot No. 3, the tray will be open to wait for closing. If there is a disc on the table, the adjustment starts immediately. If you put a disc prior to adjustment, confirm that the DL disc is set on the disc slot 3. DVD Dual Layer Disc Adjustment Steps 1. Sled Reset 2. Set Disc Type DL 3. Laser Diode (DVD) ON 4. Focus Error Check 5. Focus ON 6. Spindle Start 7. Tracking Error Level Adjust 8. Tracking Error Offset Adjust 9. Tracking ON 10. RF Level Adjustment 11. Spindle Calibration 12. Tracking Off 13. Tracking Error Level Adjust 2nd 14. Tracking Error Offset Adjust 2nd 15. Tracking ON 16. Auto Focus Gain Adjust L0 17. Auto Tacking Gain Adjust L0 18. Sled ON 19. CLV ON 20. Auto Focus Balance Adjust L0 21. Auto RFEQ Boost Adjust L0 22. Jitter measure 23. Search Check 24. Focus Jump (L0 t L1) 25. Tracking Off 26. Tracking Error Level Adjust 27. Tracking Error Offset Adjust 28. Tracking ON 29. Auto Focus Gain Adjust L1 30. Auto Tracking Gain Adjust L1 31. Sled ON 32. CLV ON 33. Auto Focus Balance Adjust L1 34. Auto RFEQ Boost Adjust L1 35. Search Check 36. All Servo Off www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 26 DVP-CX995V 2-2. Operation Commands ### Drive Manual Operation ### 2. Operation Commands 1. Search Disc (DVD Priority) 2. Search Disc (CD Priority) 3. PLAY 4. Pause 5. Stop Exit: RETURN [1] Serch Disc : DVD SDISC (F/E command) is performed by (DVD Priority) priority. [2] Serch Disc : CD SDISC (F/E command) is performed by (CD Priority) priority. [3] PLAY : Playback the current disc (DVD/CD). Start address is DVD = 0x030000 or CD = 00:00:00. [4] Pause : Pause [5] Stop : Stop 2-3. Servo Control ### Drive Manual Operation ### 3. Servo Control 1. LD DVD Off/On 2. LD CD Off/On 3. Focus Off/On 4. Spindle Off/On 5. Track Off/On 6. Sled Off/On 8. Focus Ramp Exit: RETURN On this screen, the servo on/off control necessary for replay is executed. Normally, turn on each servo from 1 sequentially and when CLVA is turned on, the usual trace mode becomes active. In the trace mode, DVD sector address or CD time code is displayed. This is not displayed where the spindle is not locked. The spindle could run overriding the control if the spindle system is faulty or RF is not present. In such a case, do not operate CLVA. [1] LD DVD : Turn on/off the laser for DVD. [2] LD CD : Turn on/off the laser for CD. [3] Focus : Turn on/off the focus servo. [4] Spindle : Turn on/off the spindle servo. [5] Track : Turn on/off the tracking servo. [6] Sled : Turn on/off the sled servo. [8] Focus Ramp : In the laser diode on and focus servo off status, repeat the focus up/down. 2-4. Track/Layer Jump 4. Track/Layer Jump 1. 1Tj FWD 2. 1Tj REV 3. 200Tj FWD 4. 200Tj REV 5. 2kTj FWD 6. 2kTj REV 9. Lj (L1->L0) FWD 0. Lj (L0->L1) REV Exit: RETURN On this screen, track jump, etc. can be performed. Only for the DVD- DL, the focus jump and layer jump are displayed in the right field. [1] 1Tj FWD : 1-track jump forward. [2] 1Tj REV : 1-track jump reverse. [3] 200Tj FWD : 200-track jump forward. [4] 200Tj REV : 200-track jump reverse. [5] 2kTj FWD : 2k-track jump forward. [6] 2kTj REV : 2k-track jump reverse. [9] Lj (L1->L0) : Layer jump. [0] Lj (L0->L1) : Layer jump. 2. Drive Manual Operation On the Test Mode Menu screen, select [2], and the manual operation menu will be displayed. For the manual operation, each servo on/ off control and adjustment can be executed manually. ## Drive Manual Operation ## 2. Operation Commands 3. Servo Control 4. Track/Layer Jump 6. Memory Check 7. Changer Manual Move 8. Changer Mecha Check Exit: RETURN Model :DVP-CX995V Revision:x.xxx Basic operation (controllable from front panel or remote commander) I/1 : Power OFF x : Servo stop Z : Stop+Eject/Loading O (RETURN) : Return to Operation Menu or Test Mode Menu > , . : Transition between sub modes of menu [1] to [9], [0] : Selection of menu and items Cursor [Q]/[q] : Increase/Decrease in manually adjusted value www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 27 DVP-CX995V [PLAY] : Loads the disc from the chucking position of Loading In the table toward inside the mechanism deck. When the Disc Load is selected, a series of operation starting from Loading – Chucking is performed. [STOP] : Moves the disc from inside the mechanism deck Loading Out to the table. When the Disc Unload is selected, a series of operation starting from Unloading – Chucking is performed. [OP/CL] : Opens and closes the door. Door Open/Close ( Z key) [UP] : Pops up the lever. Poper Up ([Q] key) [DOWN] : Pops down the lever. Poper Down ([q] key) [jog FOR]*1 : Moves the table to the right in units of the slit. Table R step Turn The table number is incremented in the direction of positive (+) number. [jog PRV]*1 : Moves the table to the left in units of the slit. Table L step Turn The table number is decremented in the direction of negative (–) number. [DISP] : When this item is selected, the 400CHG Sensor Sensor Status Check appears on the screen. ([DISPLAY] key) *1) Turn the [DISC/AMS] knob on the main unit. Display when the Sensor Status is selected in the Changer Manual Move. ## 400CHG Sensor Check ## Table 1/2/3/4 : X/X/X/X Table lock : X Load in : X Load out : X Door open : X Door close : X Poper up : X Poper down : X Disc Sensor : XXX RETURN : Exit Table 1/2/3/4 : Indicates table sensor 1/2/3/4 status. (0: Low, 1: High) Table lock : Indicates each switch status. Load in/out (0: Off, 1: On) Door open/close Poper up/down Disc Sensor : Indicates sensitivity of the disc sensor. The value is raging from 0 to 3FF. 2-6. Memory Check The display image is shown below and three screens in total can be selected. 6. Memory Check Flash Data 1 CD SL L0 L1 An.Off A xx xx xx xx An.Off B xx xx xx xx An.Off C xx xx xx xx An.Off D xx xx xx xx An.Off E xx xx xx xx An.Off F xx xx xx xx An.G.Main xx xx xx xx An.G.Side xx xx xx xx RF level xx xx xx xx FE S level xx xx xx xx Down:NextPage Exit:RETURN 6. Memory Check Flash Data 2 CD SL L0 L1 TE Level xx xx xx xx TE Offset xx xx xx xx FCS Gain xx xx xx xx TRK Gain xx xx xx xx FCS Bal.1 xx xx xx xx FCS Bal.2 xx xx xx xx RFEQ 1 xx xx xx xx RFEQ 2 xx xx xx xx VTS2 xx xx xx xx Jitter xx xx xx xx Up/Dn:Prev/NextPage Exit:RETURN 6. Memory Check Flash Data 3 CD SL L0 L1 VTS1 xx xx xx xx Up:PrevPage Exit:RETURN 2-7. Changer Manual Move On this test mode screen, selecting [7] enables the machine operation such as disc loading. The following screen appears. Display when [7] is selected in the Drive Manual Operation ## Changer Manual Move ## ENTER : Mecha Initial PLAY : Loading In STOP : Loading Out OP/CL : Door Open/Close UP : Poper Up DOWN : Poper Down jogFOR : Table R StepTurn jogPRV : Table L StepTurn DISP : Sensor Status RETURN : Exit [ENTER] : Performs initialization of mechanism deck. Mecha Initial Because the mechanical initialization is performed when the machine enters the Drive Manual Operation mode, use this item when an error such as adjustment error occurs. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 28 DVP-CX995V 2-8. Changer Mecha Check On this test mode screen, selecting [8] enables the table sensor and the disc sensor adjustment. The following screen appears. Display when [8] is selected in the Drive Manual Operation ## Changer Mecha Check ## ENTER : Mecha Initial OP/CL : Disc Load/UnLoad jogFOR : Table R StepTurn jogPRV : Table L StepTurn PLAY : Table Rotate PAUSE : Mecha Adjust DISP : Sensor Status RETURN : Exit All operations are the same as those of the Changer Manual Move except [OP/CL], [PLAY] and [PAUSE]. [OP/CL] : Loads the disc from the chucking position of Disc Load/UnLoad the table toward inside the mechanism deck ( Z key) or from inside the mechanism deck to the table. When the Disc Load is selected a series of operation starting from Door Close – Table Rotate – Chucking is performed. When the Disc UnLoad is selected a series of operation starting from Unchucking – Table Rotate – Door Open is performed. [PLAY] : Enters the Disc Sensor Adjustment Mode. Table Rotate The 400CHG Table Rotate appears on the screen. [PAUSE] : Enters the Table Sensor Adjustment Mode. Mecha Adjust The 400CHG Mecha Adjust appears on the screen. Display when [PLAY] is selected in the Changer Mecha Check. Note: Refer to page 32 for “TABLE SENSOR ADJUSTMENT”. ## 400CHG Table Rotate ## RIGHT : Turn Right LEFT : Turn Left Table 1/2/3/4 : X/X/X/X Disc Sensor : XXX RETURN : Exit [RIGHT]*1 : Rotates table counterclockwise. Turn Right [LEFT]*1 : Rotates table clockwise. Turn Left Table 1/2/3/4 : These items are the same as those of the Disc Sensor 400CHG Sensor Check. *1) Turn the [DISC/AMS] knob on the main unit. Display when [PAUSE] is selected in the Changer Mecha Check. Note: Refer to page 32 for “POP UP MECHANISM ADJUSTMENT”. ## 400CHG Mecha Adjust ## UP : Load in DOWN : Load out RIGHT : Pop Up LEFT : Pop Down Table 1/2/3/4 : X/X/X/X RETURN : Exit [UP] : Loads the disc from the chucking position of the Load in table toward inside the mechanism deck during pressing the [Q] key. [DOWN] : Loads the disc from inside the mechanism deck to Load out the table during pressing the [q] key. [RIGHT] : Pops up the lever during pressing the [w] key. Pop Up [LEFT] : Pops down the lever during pressing the [W] key. Pop Down Table 1/2/3/4 : This item is the same as that of the 400CHG Sensor Check. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 29 DVP-CX995V 3. Mecha Aging The mechanism aging is not supported. 4. Emergency History ### EMG. History ### Laser Hours CD xxh xxm DVD xxh xxm 01.00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 02.00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 Select : 1-9 Scroll : UP/DOWN (1: Last EMG.) Exit : RETURN On the Test Mode Menu screen, selecting [4] displays the information such as servo emergency history. The history information from last “1” up to “10” can be scrolled with [Q] key or [q] key. Also, specific information can be displayed by directly entering that number with the ten-key pad from [1] to [9]. The upper two lines display the laser ON total hours. Data below minutes are omitted. Clearing History Information Clearing laser hours Press [DISPLAY] and [CLEAR] keys in this order. Both CD and DVD data are cleared. Clearing emergency history Press [TOP MENU] and [CLEAR] keys in this order. Initializing setup data Press [MENU] and [CLEAR] keys in this order. The data have been initialized when “Set Up Initialized” message is displayed. The EMG. History display screen will be restored soon. 5. Version Information ### Version Information ### IF con Ver:x.xxx(xxxx) B/E Ver:xxx xxx F/E Ver:xx Model :DVP-CX995V Region :xxx(x) Exit : RETURN IF con : IC304 on the MB board B/E : IC205 on the MB board F/E : IC104 on the MB board 6. Video Level Adjustment On the Test Mode Menu screen, selecting [6] displays color bars for video level adjustment. During display of color bars, OSD disappears but the menu screen will be restored if pressing the [RETURN] key. DISPLAY SECTION DISPLAY TEST MODE Execute the Self Check Mode along the following flow. 1. Entering the Display Test Mode The Display Test mode starts if either of the following conditions is satisfied. Condition 1: With the SELF_CHECK (pin oj) of the IF CON (IC304) on the MB board kept “low”, turn the power on. (Short the CL301) Condition 2: While pressing the x key on the set when the set is in standby state, press the [RETURN] t [DISPLAY] key on the remote commander and the mode transits to the Self Check mode. When the Self Check mode started, “TEST START” is displayed on the FL tube for 2 seconds and then the Self Check proceeds to the IF CON information display. 2. Releasing the Display Test Mode To release the Self Check mode, disconnect the AC plug. 3. IF CON Information Display When enter this mode, it displays as follows. If the [DISC/AMS] knob is pressed, the test proceeds to the following FL tube GRID and SEGMENT check. I/F CON information FL tube grid and segment check SIRCS reception check Key check Jog and LED check Keyboard check START FINISH All segments turn on Model type display Destination display Version display ROM creation date display www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 30 DVP-CX995V 4. FL Tube Grid and Segment Check First, a grid lights up one after another, and when grid 16 lights up, all grids light up. Next, all grids go off, and segments are displayed while changing the patterns. A way of this display is repeated. (The interval of grid lighting is 0.2 second, and that of segment lighting is 0.4 second.) If the [DISC/AMS] knob is pressed, the test proceeds to the following SIRCS reception check. 5. SIRCS Reception Check Upon start of the SIRCS reception check, “SIRCS CHECK” is displayed on the FL tube. Once the SIRCS key code is received, the test proceeds to the following Key check. If the [DISC/AMS] knob is pressed as a cancel processing of the SIRCS reception check, the test proceeds to the following Key check. FL tube GRID check The 18th SEG of each GRID on GRID16 on ALL OFF The 1st SEG of each GRID on The 2nd SEG of each GRID on GRID1 on (0.2 sec interval) (0.2 sec interval) (0.2 sec interval) (0.4 sec interval) (0.4 sec interval) (0.4 sec interval) (0.4 sec interval) (ALL GRIDs light up) (0.2 sec interval) GRID2 on Wait for SIRCS code receiving (Once the SIRCS code is received, the check finishes.) Cancel processing (Press the [DISC/AMS] knob) SIRCS reception check SIRCS reception check finish 6. Key Check After the SIRCS reception check finished, the Key check is executed. Upon start of the Key check, “KEY CHECK” is displayed on the FL tube. 25 keys are checked as described below. Each time a key is pressed, the specified segment lights up, and at one second after all keys were pressed, all of FL tube go off and the Key check finishes. If the SIRCS key code is received as a cancel processing of the Key check, the test proceeds to the following Jog and LED check. Key check AUDIO N PROGRESSIVE ALL DISCS TRACK ;Digital MP3 SHUFFLE REPEAT 1 PGM A- B HYBRID ANGLE NTSC DISC GROUP TITLE X VCD DVD CD SA-CD Key check finish Cancel processing (SIRCS key code receiving) I/1 FL OFF TIME/TEXT PICTURE MODE REPEAT LOAD FOLDER ONE/ALL DISCS A DISC EJECT OPEN/CLOSE H X x TOP MENU MENU DISPLAY ORETURN t R T r Jog stick DISC/AMS +100 DISC CHANGE DIRECT SEARCH VIDEO www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 31 DVP-CX995V 7. Jog and LED Check After the Key check finished, the Jog and LED check is executed as follows. Upon start of the Jog and LED check, “JOG AND LED” is displayed on the FL tube. There are six LEDs. The order in which the LEDs light up when the [DISC/AMS] knob is rotated as described below. If the [DISC/AMS] knob is pressed during the Jog and LED check, the Jog and LED check finishes and the test proceeds to the following KEYBOARD check. 8. Keyboard Check After the Jog and LED check finished, the Keyboard check is executed. Once a signal is received from the keyboard, the Keyboard check finishes. The “KEYBOARD” is displayed on the FL tube until a signal is received from the keyboard. If the [DISC/AMS] knob is pressed during the Keyboard check, the Keyboard check finishes and the test proceeds to the following check. When the Keyboard check finished, it displays result of Display Test mode. (See next item) SACD (Blue) clockwise counterclockwise MULTI CHANNEL (Blue) DISC CHANGE (Amber) DIRECT SEARCH (Green) FL OFF (Amber) HDMI (Blue) 9. Display Test Mode Result Indication After the Keyboard check finished, it displays result of Display Test mode. At this time, even if a signal from a key on the set, remote commander, or keyboard is received, nothing changes. At the SIRCS reception check, Key check, Jog and LED check, and Keyboard check, if you proceed to the next check without completing current check, the check name that has not completed yet is displayed instead of “TEST OK”, as follows. If SIRCS reception check has not completed “SIRCS NG” (If JOG dial is pressed during SIRCS reception check) If KEY check has not completed “KEY NG” (If SIRCS key code is received during KEY check) If JOG and LED check has not completed “JOG LED NG” (If JOG dial is pressed without rotating JOG dial even once during JOG and LED check) If KEYBOARD check has not completed “KEYBOARD NG” (If JOG dial is pressed during a signal reception from keyboard) Also, if two or more checks have not completed yet All four checks are erroneous “S KY J KB NG” Three checks are erroneous “S J KB NG” “S KY KB NG” Two checks are erroneous “ KY KB NG” “ KY J NG” Each error is displayed at the fixed position of the FL tube (not left aligned), and the items that have completed are blank. Note: The alphabets mentioned above denote the following checks. S : SIRCS reception check KY : Key check J : Jog and LED check KB : Keyboard check NG : There are error items. Using the grid 1 to grid 12, the following characters are displayed. “TEST OK” Self check mode finish www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 32 DVP-CX995V SECTION 5 MECHANICAL ADJUSTMENTS POP UP MECHANISM ADJUSTMENT 1. Connect the AC plug of the set to AC consent, then the set enters standby mode. 2. Press the [TOP MENU], [CLEAR] and I/1 keys on the remote commander in this order, then the set enters the DVD Test Mode. 3. Select “2. Drive Manual Operation” by pressing the [2] key. 4. Select “8. Changer Mecha Check” by pressing the [8] key. 5. Press the [ENTER] key, then the CDM initializies. 6. Press the [PAUSE] key, then the table rotates to the mechanical adjustment position, the door opens and the table locks. (Fig. 1) 7. Keep pressing the [w] key to raise the pop up part. 8. Loosen the adjusting screw, move the screwdriver left and right until the lever (POP UP) does not touch the slit wall, and secure the screw. (Fig. 2) The following keys have special functions in this mode. [Q] key : Loading mechanism IN operation [q] key : Loading mechanism OUT operation [w] key : Pop up part UP operation [W] key : Pop up part DOWN operation TABLE SENSOR ADJUSTMENT After the Pop Up Mechanism Adjustment, perform this adjustment continuously. 1. Loosen the fixing screw. Moving the holder little by little, stop it at a boundary point where the PROGRESSIVE LED (blue) goes off and the SA-CD LED (white) lights up. If the holder is moved in reverse direction, stop the holder at a point where the SA-CD LED goes off and the PROGRESSIVE LED lights up. 2. Moving the table right and left with a hand after the screw is fixed, the table will move by the play of the table. If the LEDs light up alternately, the adjustment will be performed correctly. (Fig. 3) Fig. 1 Fig. 2 Fig. 3 Holder (table sensor 400) S tight, screw (PTTWH3 × 6) Swing Table (400) assembly At this position,this part will be locked. Lever (POP-UP 400) Fix to the center so that the lever (POP-UP 400) does not touch the slit. Cover (chassis 400) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 33 DVP-CX995V SECTION 6 ELECTRICAL ADJUSTMENTS Instruments required: 1) Color monitor TV 2) Oscilloscope 1 or 2 phenomena, band width over 100 MHz, with delay mode 3) Frequency counter (over 8 digits) 4) Digital voltmeter 5) Remote commander (RM-ASP001) 6) CD reference disc LUV-P01 (4-999-032-01) YEDS-18 (3-702-101-01) PATD-012 (4-225-203-01) 7) DVD reference disc TDV-520CS0 (J-2501-236-A) (single layer) (NTSC) HLX-503 (J-6090-069-A) (single layer) (NTSC) HLX-504 (J-6090-088-A) (single layer) (NTSC) TDV-540C (J-2501-235-A) (dual layer) (NTSC, Opposite) HLX-501 (J-6090-071-A) (dual layer) (NTSC) HLX-505 (J-6090-089-A) (dual layer) (NTSC) 8) SA-CD reference disc HLXA-509 (J-6090-090-A) 9) Extension Cable (J-2501-199-A) 6-1. OPTICAL TRAVERSE UNIT CHECK In the case of quality judgement when the defect of the optical traverse unit like the skip etc. is thought, and in case of operation confirming when replacing optical traverse unit, select “ALL” of “1. DRIVE AUTO ADJUSTMENT” in the test mode (refer to page 23, 25), adjust DVD-SL (single layer), CD and DVD-DL (dual layer), and confirm whether the result of each setting value is the range of the following specification. DVD-SL CD DVD-DL L0 L1 An.Off.A 20 to E0 20 to E0 20 to E0 – An.Off.B 20 to E0 20 to E0 20 to E0 – An.Off.C 20 to E0 20 to E0 20 to E0 – An.Off.D 20 to E0 20 to E0 20 to E0 – An.Off.E – 20 to E0 – – An.Off.F – 20 to E0 – – An.G.Main 0E to 1C 0E to 1A 1D to 28 1D to 28 An.G.Side – 0C to 1C – – RF level 70 to F0 70 to F0 60 to F0 60 to F0 FE S L0 74 to FF 74 to FF 54 to FF – FE S L1 – – – 54 to FF VTS2 00 to 10 – – – TE levDVD 28 to 48 – 28 to 48 28 to 48 TE levCD – 34 to 60 – – TE Offset D0 to FF A0 to CC 20 to E0 20 to E0 00 to 30 00 to 30 00 to 30 FCS Gain 20 to 3F 18 to 38 20 to 48 20 to 48 TRK Gain 30 to 50 30 to 50 30 to 50 30 to 50 FCS Bal.1 – – – – FCS Bal.2 36 to 4F 36 to 4F 36 to 4F 36 to 4F REFQ1 – – – – REFQ2 0C to 30 14 to 24 0C to 30 0C to 30 Jitter 07 to 14 07 to 0F 07 to 14 – 6-2. POWER SUPPLY CHECK Mode: E-E Instrument: Digital voltmeter EVER +3.3 V Check Check point JL381 on the AV board Specification 3.3 ± 0.2 V SW +4.5 V Check Check point JL378 on the AV board Specification 4.5 ± 0.2 V SW +5 V Check Check point JL382 on the AV board Specification 5.0 ± 0.3 V SW +12 V Check Check point JL376 on the AV board Specification 12.0 ± 1.0 V EVER +12 V Check Check point JL383 on the AV board Specification 12.0 ± 1.0 V SW –12 V Check Check point JL373 on the AV board Specification –12.0 ± 1.0 V EVER –12 V Check Check point JL372 on the AV board Specification –12.0 ± 1.0 V Checking method: 1) Confirm that each voltage satisfies the specification. 1.0 +0.04 Vp-p –0.02 6-3. ADJUSTMENT OF VIDEO SYSTEM 6-3-1. Video Level Adjustment This adjustment is made to satisfy the NTSC standard, and if not adjusted correctly, the brightness will be too large or small. Mode Video level adjustment in test mode Signal Color bars Check point VIDEO LINE OUT connector (J103) (75 Ω terminated) Instrument Oscilloscope Adjusting element RV501 Specification 1.0 + – 0 0 . . 0 0 4 2 Vp-p Adjusting method: 1) In the Test Mode Menu, select the “6. Video Level Adjustment” so that color bars are generated. 2) Adjust the RV501 to attain 1.0 + – 0 0 . . 0 0 4 2 Vp-p. Fig. 6-1 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 34 DVP-CX995V 1.0 ± 0.05 Vp-p 6-3-5. Checking Component Video Output Y This checks component video output Y. If it is incorrect, correct brightness will not be attained when connected to, for instance, projector. Mode Video level adjustment in test mode Signal Color bars Check point COMPONENT VIDEO OUT (Y) connector (J102) (75 Ω terminated) Instrument Oscilloscope Specification 1.0 ± 0.05 Vp-p Checking method: 1) In the Test Mode Menu, select the “6. Video Level Adjustment” so that color bars are generated. 2) Confirm that the Y level is 1.0 ± 0.05 Vp-p. Fig. 6-5 1.0 ± 0.05 Vp-p 6-3-3. Checking S Video Output S-Y Check S-terminal video output. If it is incorrect, pictures will not be displayed correctly in spite of connection to the TV with a S- terminal cable. Mode Video level adjustment in test mode Signal Color bars Check point S VIDEO OUT (S-Y) connector (J101) (75 Ω terminated) Instrument Oscilloscope Specification 1.0 ± 0.05 Vp-p Checking method: 1) In the Test Mode Menu, select the “6. Video Level Adjustment” so that color bars are generated. 2) Confirm that the S-Y level is 1.0 ± 0.05 Vp-p. Fig. 6-3 6-3-2. Progressive Video Output Level Adjustment This adjusts progressive video output level. If it is incorrect, correct brightness will not be attained when connected to, for instance, projector. Mode Video level adjustment in test mode Signal Color bars Check point COMPONENT VIDEO OUT (Y) connector (J102) (75 Ω terminated) Instrument Oscilloscope Adjusting element RV500 Specification 1.0 + – 0 0 . . 0 0 4 2 Vp-p Adjusting method: 1) In the Test Mode Menu, select the “6. Video Level Adjustment” so that color bars are generated. 2) Adjust the RV500 to attain 1.0 + – 0 0 . . 0 0 4 2 Vp-p. Fig. 6-2 1.0 +0.04 Vp-p –0.02 A 6-3-4. Checking S Video Output S-C This checks whether the S-C satisfies the NTSC standard. If it is not correct, the colors will be to dark or light. Mode Video level adjustment in test mode Signal Color bars Check point S VIDEO OUT (S-C) connector (J101) (75 Ω terminated) Instrument Oscilloscope Specification A = 286 ± 30 mVp-p (NTSC) Checking method: 1) In the Test Mode Menu, select the “6. Video Level Adjustment” so that color bars are generated. 2) Confirm that the S-C burst is “A”. Fig. 6-4 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 35 DVP-CX995V 700 ± 50 mVp-p CN301 1 14 JL373 JL372 JL378 JL376 JL381 JL382 RV501 Video Level Adjustment RV500 Progressive Video Output Level Adjustment JL383 – AV Board (Conductor Side) – Adjustment Location: 6-3-6. Checking Component Video Output B-Y This checks component video output B-Y. If it is incorrect, correct colors will not be displayed when connected to, for instance, projector. Mode Video level adjustment in test mode Signal Color bars Check point COMPONENT VIDEO OUT (PB/CB) connector (J102) (75 Ω terminated) Instrument Oscilloscope Specification 700 ± 50 mVp-p Checking method: 1) In the Test Mode Menu, select the “6. Video Level Adjustment” so that color bars are generated. 2) Confirm that the B-Y level is 700 ± 50 mVp-p. Fig. 6-6 6-3-7. Checking Component Video Output R-Y This checks component video output R-Y. If it is incorrect, correct colors will not be displayed when connected to, for instance, projector. Mode Video level adjustment in test mode Signal Color bars Check point COMPONENT VIDEO OUT (PR/CR) connector (J102) (75 Ω terminated) Instrument Oscilloscope Specification 700 ± 50 mVp-p Checking method: 1) In the Test Mode Menu, select the “6. Video Level Adjustment” so that color bars are generated. 2) Confirm that the R-Y level is 700 ± 50 mVp-p. Fig. 6-7 700 ± 50 mVp-p www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 36 DVP-CX995V 6-4. DISC DETECT SENSOR ADJUSTMENT Be sure to perform this adjustment after sensor adjustment in MECHANICAL ADJUSTMENT. (See page 32) Connection: Waveform: 1. Connect the oscilloscope to pins 1, 2 and 3 of CN301 on the MB board. 2. Check that no discs are loaded in the unit. 3. Perform from step 1 to step 5 in Pop Up Mechanism Adjustment. (See page 32) 4. Press the [PAUSE] key, then the table starts to rotate in the clockwise direction. 5. Turn the RV301 on MB board and adjust so that the H portion A of DSENS_OUT waveform is twice the width of the H portion B of HH_OUT waveform. Adjustment Location: MB board 6. Loosen the fixing screw, move the mounting board (SENSOR), and secure the mounting board (SENSOR) at the point the H portion of the HH_OUT waveform comes the center of the H portion of the DSENS_OUT waveform. DSENS_OUT HH_OUT CH1 CH2 DSENS_OUT HH_OUT CH1 CH2 A A = 2 × B B S tight, screw (PTTWH3 × 6) D. SENS OUT board DSENS_OUT HH_OUT CH1 CH2 Should be at the center DSENS_OUT: Pin 3 GND: Pin 2 HH_OUT: Pin 1 oscilloscope CH1 CH2 DSENS_OUT GND HH_OUT MB board CN301 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DVP-CX995V 37 37 DVP-CX995V CN301 RV301 Disc Detect Sensor Adjustment – MB Board (Side A) – 3 1 Adjustment Location: w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DVP-CX995V 38 38 DVP-CX995V SECTION 7 DIAGRAMS 7-1. BLOCK DIAGRAM – SERVO Section – PARALELL DATA BUS ADDRESS BUS RF FILTER Q105 LOW-PASS FILTER IC101 (1/3) OSC BUFFER IC201 A CENTER VOLTAGE GENERATOR IC101 (3/3) REFERENCE VOLTAGE GENERATOR IC101 (2/3) AUTOMATIC POWER CONTROL (FOR DVD) Q101, 102 CPU IC205 DVD INTERFACE IC104 OPTICAL TRAVERSE UNIT (DBU-3) TRACKING/FOCUS COIL DRIVE, SPINDLE/SLED MOTOR DRIVE IC102 LEVEL SHIFT Q310 BUFFER IC209 B C D E F LD (DVD) PD AUTOMATIC POWER CONTROL (FOR CD) Q103, 104 LD (CD) SPDIR 70 MUTE_SP 36 MUTE_DRV 37 SP 44 SLED 29 DISC 28 TACT 34 FACT 33 A 6 B 8 C 14 D 12 E 21 F 20 SW (DVD/CD) DVD/CD 43 INLIM INLIM 45 FCS+ DO1– 36 FCS– DO1+ 37 LMD1 93 LMD2 94 LD1 89 LD2 90 MUTE12 19 MUTE34 20 MUTE5 21 RFIN 3 RFOUT 4 B-DATA 16 OUT-DATA 64 B-BCLK 17 OUT-CLK 61 B-FLAG 18 OUT-DVALID 63 WCLK 20 OUT-EVALID 59 RSERROR 187 OUT-ERR 58 IRQ (0) 127 IRQ_FE 71 FE_RST 186 RESET_N 81 BE_SCL 195 SCL 66 BE_SDA BE_SCL BE_SDA 194 SDA 67 PIX-CLK 120 IF_TXD 197 BE_A_MUTE 188 B-SYNC 19 B-V4 21 OUT-SYNC 65 RFSACD 99 IN1– 1 TRK+ DO2+ 35 TRK– DO2– 34 IN2– 4 SLEDGEA+ DO3+ 32 SLEDGEA– DO3– 31 IN3– 7 SLEDGEB+ DO4+ 30 SLEDGEB– DO4– 29 IN4– 10 SPINDLE+ DO5– 27 SPINDLE– DO5+ 28 IN5– 13 OPIN2– 41 OPIN2+ 42 OPOUT2 3.3V-D (MB) VREF (2.7V) 40 REF 32 FREIN 87 141 – 148, 151 – 158 161 – 170, 173 – 183 CPU-DATA (0) – CPU-DATA (15) CPU-ADR (1) – CPU-ADR (21) CPU-DATA (0) – CPU-DATA (15) CPU-ADR (1) – CPU-ADR (7) 29 – 36, 38 – 45 DQ0 – DQ14, DQ15A-1 25 – 16, 10 – 1, 48 A1 – A21 W 11 G 28 E 26 RP 12 FLASH MEMORY IC202 CPU-CE (1) 132 RESET 124 CPU-CE (3) 134 CPU-OE 117 CPU-BE (0) 128 CPU-CE (2) 133 DAC-PCMCLK 55 SPDIF-OUT 57 SCLK 208 SO 207 ADAC_CS 22 VIDEO_RST 9 IRQ (1) 126 SQUEEZE 191 YC_CLKOUT VIDEO_RST H_INT_B SQUEEZE YC_CLK DIGITAL VIDEO SPDIF SACD DAC-PCMCLK SACD, I2S YC0 – YC7 YC0 – YC7 3 IRQ (2) 125 CPU-WAIT 131 CPU-RW 130 IF_RXD 200 BE_CS 13 BE_BUSY 11 TMODE_SW BE_RXD BE_TXD BE_CS BE_BUSY TMODE_SW 103 SCLK SO ADAC_CS I2S_DATA_OUT 6 I2S_BCLK_OUT 7 I2S_BFLAG_OUT 8 I2S_WCK_OUT 196 I2S_SYNC_OUT 193 FUR_RST SA_CS SA_IRQ SA_WAIT SA_RW I2S_DATA_OUT I2S_BCLK_OUT I2S_BFLAG_OUT I2S_WCK_OUT I2S_SYNC_OUT FUR_RST 1 29 – 36, 38 – 45 DQ0 – DQ14, DQ15A-1 25 – 16, 10 – 1, 48 2, 4, 5, 7, 8, 10, 11, 42, 44, 45, 47, 48, 50, 51, 53 22 – 26, 29 – 35, 20, 21 84 – 93, 97 – 102 58 – 63, 66 – 73 A1 – A21 W 11 G 28 E 26 RP 12 FLASH MEMORY IC204 A0 – A11, BA0, BA1 SMI-ADR (0) – SMI-ADR (13) SMI-DATA (0) – SMI-DATA (15) DQ0 – DQ15 SD-RAM IC203 SMI-CLKOUT 95 CLK 38 SMI-CLKIN 82 SMI-CS (0) 74 CS 19 SMI-RAS 76 RAS 18 SMI-CAS 77 CAS 17 SMI-WE 78 WE 16 SMI-DQML 79 LDQM 15 SMI-DQMU 80 UDQM 39 39 – 46 OPTICAL TRANSCEIVER IC301 B F G RFSACD A DAC-LRCK 56 DAC-SCLK 51 PCM (5.1CH) DAC-PCMOUT0 52 DAC-PCMOUT1 53 DAC-PCMOUT2 54 DAC-PCMOUT3 DAC-LRCK DAC-SCLK FLFR CSW SLSR DLDR 2 D DAC E PCM (HDMI) C H BE_RST J I2C X201 27MHz K BE_A_MUTE P CPU-I/F N SA_SYS_CLK L COAXIAL PCM/DTS/ DOLBY DIGITAL DIGITAL OUT OPTICAL • SIGNAL PATH : PLAY (VIDEO) : PLAY (AUDIO) (Page 39) (Page 40) (Page 40) (Page 39) (Page 39) (Page 39) (Page 39) (Page 39) (Page 39) (Page 40) (Page 39) (Page 39) (Page 39) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DVP-CX995V 39 39 DVP-CX995V 7-2. BLOCK DIAGRAM – AUDIO Section – SACD MEDIA PLAYER IC401 D/A CONVERTER IC501 SD-RAM IC403 H_CSN 24 AGCINP 35 H_IRQN 28 H_WAIT 27 H_RWN 26 87, 90, 91, 93 – 98, 100 – 105, 107 64 – 68, 70 – 75, 77 – 79 D_DQO – D_DQ15 D-ADDR0 – D_ADDR13 25, 23, 22, 16 – 11, 9 – 5, 3, 2 1, 128 – 123 H_DQ0 – H_DQ15 H_A1 – H_A6, H_A_SEL 2, 4, 5, 7, 8, 10, 11, 13, 42, 44, 45, 47, 48, 50, 51, 53 20 – 26, 29 – 35 DQ0 – DQ15 A0 – A11, BA0, BA1 B_DATA/BE_DAT0 45 CLK 38 D_CLK 86 WE 16 D_WEN 80 RAS 18 D_RASN 81 CAS 17 D_CASN 82 UDQM SYSTEM CONTROLLER IC304 (1/2) 39 D_UDQM 88 LDQM 15 D_LDQM 89 DSD_PCM_0 108 DSD_PCM_1 109 B_BCLK/SDCLK 46 B_FLAG/SERR 42 B_WCLK/SENB 44 B_SYNC/SYNC 43 RESETN 122 DSD_PCM_2 110 DSD_PCM_3 111 DSD_PCM_4 113 DSD_PCM_5 114 DSD_PCM_11 121 DSD_PCM_9 120 DSD_PCM_8 117 ROUT1– 47 SACD H SYS_CLK 21 H_PROCCLOCK 18 SACD, I2S SA_CS SA_IRQ SA_WAIT SA_RW I2S_DATA_OUT I2S_BCLK_OUT I2S_BFLAG_OUT I2S_WCK_OUT I2S_SYNC_OUT FUR_RST BE_RXD0 46 BE_TXD 45 TMODE_SW 83 BE_CS 23 BE_BUSY BE_RXD0 BE_TXD TMODE_SW BE_CS BE_BUSY 33 G RFSACD A AUD_CLK 29 SA_SYS_CLK L BE_A_MUTE P CPU-I/F N VMUTE R BE_RST J CCLK/SCL 19 CDTI/SDA 20 CSN/CAD1 21 LRCK 17 BICK 9 DSDL1 25 DSDR1 26 DSDL3 29 DSDR3 30 DSDL2 27 DSDR2 28 DSDL4 23 DSDR4 24 DCLK 22 PCM (5.1CH) SDTI1 14 MCLK 10 SDTI2 16 SDTI3 15 SDTI4 SCLK SO ADAC_CS DAC-LRCK DAC-SCLK FLFR CSW SLSR DLDR 13 D DAC E DAC-PCMCLK F HDMI_MCLK Q OSC BUFFER IC206 LINE AMP IC202 ROUT1+ 48 LOUT1– 1 LOUT1+ 2 L FRONT R MUTING Q203 MUTING Q204 ROUT3– 39 LINE AMP IC204 ROUT3+ 40 LOUT3– 41 LOUT3+ 42 CENTER WOOFER MUTING Q207 MUTING Q208 ROUT2– 43 LINE AMP IC203 ROUT2+ 44 LOUT2– 45 LOUT2+ 46 L REAR R MUTING Q205 MUTING Q206 ROUT4– 32 DZF23 5 DZFR1 4 DZFL1 3 LINE AMP IC201 ROUT4+ 33 LOUT4– 37 LOUT4+ 38 L 1 2 R MUTING Q201 MUTING Q202 J201 5.1CH OUTPUT J103 (1/2) AUDIO LINE OUT MUTING CONTROL Q307 – 309 MUTING CONTROL Q304 – 306 MUTING CONTROL Q301 – 303 AMUTE 68 VMUTE 69 BE_RST 34 CPU-DATA (0) – CPU-DATA (15) CPU-ADR (1) – CPU-ADR (7) PDN 8 • SIGNAL PATH : PLAY (VIDEO) : PLAY (AUDIO) (Page 38) (Page 38) (Page 40) (Page 38) (Page 38) (Page 38) (Page 38) (Page 38) (Page 38) (Page 38) (Page 38) (Page 40) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DVP-CX995V 40 40 DVP-CX995V 7-3. BLOCK DIAGRAM – VIDEO Section – RESET 42 CSDA 44 VIDEO D/A CONVERTER IC500 INTERLACE/PROGRESSIVE CONVERTER IC401 VIDEO AMP IC102 HDMI TRANSMITTER IC600 44 V 33 VIDEO_OUT 24 Y_OUT 22 CB_OUT 20 CR_OUT 30 TX0+ 29 TX0– Y_OUT C_OUT 47 RSET1 3 VIDEO_IN 43 Y 8 Y_IN 42 C 6 C_IN 39 Y/G 12 Y_IN 148 QCLK 60 IDCK 17 RAS 106 RAS 16 CAS 108 CAS 15 WE 109 WE 36 DQMU 107 DQM 14 DQML 134 QV 2 VSYNC 135 QH 1 HSYNC 136 QDE 80 DE 5 SPDIF 10 SD0 12 SCK 11 WS 17 INT SPDIF DLDR DAC-SCLK DAC-LRCK H_INT_B HDMI_MCLK 6 MCLK 38 CB/R 15 CB_IN 37 CR/B 17 CR_IN 7 MUTE1 16 MUTE2 2 – 9, 12, 13 14 – 18, 26 – 30 53 – 55, 58 –62 P_Y (0) – P_Y (9) P_C (0) – P_C (9) S (2) – S (9) 56 – 47 43 – 34 56 – 49 68 – 61 YO0 – YO9 CO0 – CO9 SO2 – SO9 23 – 30 SI2 – SI9 YC0 – YC7 SQUEEZE 32 CLKIN 10 CLKI YC_CLK 63 CLKIN_2 CSCL 43 33 RESET8 22 SCL 21 SDA BE_SCL BE_SDA VIDEO_RST I2C DIGITAL_VIDEO • SIGNAL PATH : VIDEO (COMPOSITE) : Y/C : PLAY (VIDEO) : YUV : PLAY (AUDIO) : COMPONENT VIDEO VIDEO LEVEL RV501 35 RSET2 59 CLKO 5 SDA 6 SCL PROGRESSIVE VIDEO OUTPUT LEVEL RV500 J102 1 2 3 4 5 6 7 8 COMPONENT VIDEO OUT J600 HDMI OUT Y PR/CR PB/CB VIDEO LINE OUT J103 (2/2) 1 2 S VIDEO OUT J101 1 2 29 31 WIDE ON/OFF SWITCH Q103, 104 DATA0+ DATA0– 18 7 9 +5V POWER +5V POWER (HMDI OUT) 33 TX1+ 32 TX1– DATA1+ DATA1– 4 6 36 TX2+ 35 TX2– DATA2+ DATA2– 1 3 19 DSDA 20 DSCL 18 HPD 27 TXC+ 26 TXC– CLOCK+ CLOCK– 10 12 SDL (5V) SCL (5V) 16 15 HOT PLUG DET 19 67, 65 – 61, 58, 57 D8 – D15 151 – 154, 157 – 160 QG0 – QG7 79 – 75, 70 – 68 D0 – D7 92 – 98, 101 – 105 MA0 – MA11 19 – 24, 27 – 32 A0 – A11 DQ0 – DQ15 113 – 120, 123 – 130 2, 3, 5, 6, 8, 9, 11, 12, 39 40, 42, 43, 45, 46, 48, 49 MD0 – MD15 138 – 141, 143 – 146 QB0 – QB7 D16 – D23 164 – 167, 170 – 173 QR0 – QR7 LEVEL SHIFT IC605 LEVEL SHIFT IC602 8 NRST SD-RAM IC402 B K VMUTE R Q PCM (HDMI) C 35 CLK 83 MCLK (Page 39) (Page 38) (Page 38) (Page 38) (Page 39)w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DVP-CX995V 41 41 DVP-CX995V 7-4. BLOCK DIAGRAM – PANEL, TABLE, POWER SUPPLY Section – DSENS_OUT HH_OUT 3 1 CN301 (FOR ADJUSTMENT) 4 5 1 DATA CLK +5V SW+5V (PANEL) KEYBOARD DISABLE SWITCH Q1008, Q1009 54 – 40 20 – 3 INVERTER TRANSFORMER T1081 EVER–12V –5V REGULATOR IC101 SW+4.5V SW–12V (AV) B– SWITCH Q371, 372 RECT D1081 – 1084 +5V REGULATOR IC302 B– SWITCH Q351 SW–12V SW+12V SW+5V B+ SWITCH Q373, 374 SWITCHING REGULATOR LEVEL SHIFT Q303, 304 REGULATOR Q931 EVER+12V B+ SWITCH Q352, 353 OSC Q1081, 1082 AV–5V +3.3V REGULATOR IC604 +1.8V REGULATOR IC601 HDMI+1.8V +2.5V REGULATOR IC501 +2.5V (VIDEO DAC) +1.8V REGULATOR IC400 +1.8V (AV) +3.3V REGULATOR IC502 3.3V-V HDMI+3.3V 5V-A (MB), 5V-D (MB), SW+5V (AV), SW+5V (PANEL) SW+4.5V +3.3V REGULATOR IC371 +3.3V REGULATOR IC208 RESET SIGNAL GENERATOR IC306 +1.8V REGULATOR IC207 SW+4.5V P-CONT EVER+3.3V 1.8V-A (MB), 1.8V-D (MB) 3.3V-A (MB), 3.3V-D (MB) EVER+3.3V (PANEL), EVER+3.3V (MB) OPAMP–B OPAMP+B A+5V TO FLUORESCENT INDICATOR TUBE FL1001 –30V REGULATOR Q1083 M603 (DOOR) DISC DETECT D81, Q81 DISC DETECT SENSOR GRID DRIVE Q1010 DOOR MOTOR DRIVE IC961 (1/2) WAKE-UP SWITCH IC302, 305 REMOTE CONTROL RECEIVER IC1002 LED DRIVE Q1001 – 1004, Q1006, Q1007 FLUORESCENT INDICATOR TUBE FL1001 FL DRIVER IC1001 SYSTEM CONTROLLER IC304 (2/2) VDISP–30V +5V REGULATOR IC603 +5V POWER (HDMI OUT) +7V REGULATOR IC103 BU DRIVER +7V TABLE MOTOR B+ SW–12V (M) SW+12V (M), 12V-D F1 F2 MUTING B+ OPAMP+B D301 RESET 16 P_CONT 70 PON_CHECK 95 DRM+ 47 (AC IN) Q306 Q305 CLOSE OPEN S611 (DOOR OPEN/CLOSE) S612 (POP-UP) UP DOWN JOG_B 9 JOG_A 8 LED7 LED0 – LED3, LED5, LED6 79 16G 1G – 15G 52, 59, 53, 60 TSENS1 – TSENS4 P1 – P18 39 OSC0 65 OOSC1 66 DA 70 CP 69 CS 68 RESET 67 LED DRIVE Q307 D801 (TABLE ILLUMINATION) DRM– 48 FLDSDATA 56 FLDSCLK 57 FLDCS 62 FLDRST 61 D1001 – D1004, D1101, D1102 WAKE-UP SWITCH Q301, 302 SIRCS 31 KBDOUT Q1009 Q1008 67 KBCOUT 66 KBD_IN 54 KBC_IN 58 KEY_INT 20 73 – 76, 89, 90 KEY0 – KEY4 S1001 – S1004, S1006 – S1009, S1101, S1112 KEY0, KEY1 2, 1, 100 – 98 DISC/AMS PUSH ENTER RE1101 J821 KEYBOARD JG1101 (JOG STICK) PUSH ENTER 14 15 X301 5MHz 5.0M 5.0M M M602 (LOADING) LOADING MOTOR DRIVE IC961 (2/2) LDM+ 49 DR_SW 92 LDM– 50 DSENS_OUT 29 HH_OUT 30 M M601 (TABLE) TABLE MOTOR DRIVE IC941 LEVEL SHIFT Q941, 942, Q951, 952 TABLE ADDRESS SENSOR IC81 – 84 TBM+ 39 TBM– 40 M OUT IN S621 (LOADING DETECT) RV301 S622 (LOCK) LD_SW 91 DSENS_IN 94 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DVP-CX995V 42 42 DVP-CX995V • Note for Printed Wiring Boards and Schematic Diagrams Note on Printed Wiring Board: • X : parts extracted from the component side. • Y : parts extracted from the conductor side. • f : internal component. • : Pattern from the side which enables seeing. (The other layers' patterns are not indicated.) Caution: Pattern face side: Parts on the pattern face side seen from (Side B) the pattern face are indicated. Parts face side: Parts on the parts face side seen from (Side A) the parts face are indicated. Caution: Pattern face side: Parts on the pattern face side seen from (Conductor Side) the pattern face are indicated. Parts face side: Parts on the parts face side seen from (Component Side) the parts face are indicated. • MB board and AV board are multi-layer printed board. However, the patterns of intermediate-layer have not been in- cluded in diagram. • Indication of transistor C B These are omitted. E Q Note on Schematic Diagram: • All capacitors are in µF unless otherwise noted. (p: pF) 50 WV or less are not indicated except for electrolytics and tantalums. • All resistors are in Ω and 1/4 W or less unless otherwise specified. • f : internal component. • C : panel designation. • A : B+ Line. • B : B– Line. • H : adjustment for repair. • Voltages and waveforms are dc with respect to ground under no-signal conditions. no mark : DVD PLAY ( ) : SACD PLAY [ ] : CD PLAY ∗ : Impossible to measure • Voltages are taken with a VOM (Input impedance 10 MΩ). Voltage variations may be noted due to normal produc- tion tolerances. • Waveforms are taken with a oscilloscope. Voltage variations may be noted due to normal produc- tion tolerances. • Circled numbers refer to waveforms. • Signal path. c : PLAY (VIDEO) J : PLAY (AUDIO) L : VIDEO (COMPOSITE) E : Y/C a : YUV p : COMPONENT VIDEO Note: The components identi- fied by mark 0 or dotted line with mark 0 are criti- cal for safety. Replace only with part number specified. Note: Les composants identifiés par une marque 0 sont critiques pour la sécurité. Ne les remplacer que par une pièce portant le numéro spécifié. • Circuit Boards Location LED board DOOR MOTOR board DRIVER board DOOR SW board SENSOR board D. SENS OUT board D. SENS IN board LOADING SW board LOCK SW board RF TRANSLATION board switching regulator AV board MB board PANEL-L board PANEL-R board KEY BOARD board LOADING MOTOR board w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DVP-CX995V 43 43 DVP-CX995V 7-5. PRINTED WIRING BOARD – RF TRANSLATION Board – • See page 42 for Circuit Boards Location. : Uses unleaded solder. CN003 CN001 CN002 1-863-815- 11 (11) RF TRANSLATION BOARD MB BOARD CN101 S OPTICAL TRAVERSE UNIT (DBU-3) A B C D 1 2 3 4 SL001 (Page 44) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DVP-CX995V 44 44 DVP-CX995V 7-6. PRINTED WIRING BOARD – MB Board (Side A) – • See page 42 for Circuit Boards Location. : Uses unleaded solder. RB215 CN305 R1054 R1053 R1052 R1051 R1050 R1049 R1048 R1047 RB208 RB210 C402 C403 C222 C225 R421 R418 R415 R414 R407 C229 C238 C410 C411 C416 C417 C418 C425 C428 C429 R213 IC205 R257 R256 R255 R254 R253 R252 R251 R1005 R1004 R249 R248 R246 CN205 FL402 IC401 R243 R245 CN203 C505 C507 CN501 RB216 C315 R1060 R1059 R1058 R1057 R613 C266 C265 C264 C262 C263 C250 C251 FB221 FB220 FB219 Q305 Q304 C301 C305 R372 FB211 D202 R381 Q306 CN307 CN102 C328 C327 R305 R306 R307 R309 C309 C310 C313 C314 Q303 C317 C206 C319 L203 C259 C257 IC202 Q302 Q301 FL203 FL202 FL201 IC306 IC305 IC304 R368 R369 RV301 IC302 C175 C177 R201 R202 R208 R311 R225 R226 R229 R230 R231 R232 R233 R234 R235 C209 R238 R240 IC206 R258 R260 R266 R267 R273 R275 R276 R277 R278 R279 R281 R280 C102 R289 R313 C178 C113 C114 D301 D101 C420 R322 R333 C323 R341 R347 C242 C124 C230 C126 C127 C129 C134 C219 C218 C216 C208 R1022 R1023 R1024 R1025 C204 R1033 R1034 R353 R354 CN304 R358 C142 R1055 RB206 RB202 RB203 RB205 C145 C146 C149 Q307 CN301 C203 C202 C201 CN303 X201 R1028 C153 R197 R196 R194 R185 R184 C154 R181 C155 R177 R176 R175 R174 R173 R170 R169 R168 R167 R166 R161 R165 R164 R163 R162 R160 R159 R158 R157 R154 R152 R149 R148 R143 C156 R141 R121 R114 R113 R112 R111 R107 R106 R105 R104 R103 R102 Q105 L105 IC104 IC103 IC102 IC201 C159 CN101 C165 C170 R1002 C195 C194 R1001 C171 C191 C188 C186 C172 C173 RB201 R1074 X301 R1056 MB BOARD (SIDE A) 1-863-799- 11 RF TRANSLATION BOARD CN003 S AV BOARD CN400 A AV BOARD CN306 B AV BOARD CN302 G E 1 3 5 4 1 3 5 4 E E E E E E E 1 10 1 30 80 81 100 50 31 51 1 1 4 9 FOR ADJUSTMENT DRIVER BOARD CN901 C SENSOR BOARD CN81 D LED BOARD CNP504 E PANEL-L BOARD CN1003 F NC 3 1 2 5 1 NC E A B C D E F G H 1 2 3 4 5 6 7 8 9 10 11 12 SL301 SL302 (Page 43) (Page 58) (Page 58) (Page 59) (Page 62) (Page 60) (Page 66) (Page 64) D101 F-10 D202 G-3 D301 E-8 IC102 C-2 IC103 B-3 IC104 C-4 IC201 H-3 IC202 F-6 IC205 F-4 IC206 E-2 IC302 E-10 IC304 F-9 IC305 E-10 IC306 E-10 IC401 C-7 Q105 B-4 Q301 F-8 Q302 E-8 Q303 G-9 Q304 G-10 Q305 G-9 Q306 G-9 Q307 G-8 • Semiconductor Location Ref. No. Location w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DVP-CX995V 45 45 DVP-CX995V 7-7. PRINTED WIRING BOARD – MB Board (Side B) – • See page 42 for Circuit Boards Location. : Uses unleaded solder. R304 RB204 R1003 RB404 RB403 RB402 C220 C221 R1042 R1041 R1040 R1039 C404 C405 R429 R428 C223 R425 C224 C227 R417 C228 C234 RB214 RB213 C409 C412 C413 C414 C415 C424 C426 RB212 FL204 IC203 R236 R269 R268 R237 FL401 R242 Q101 L103 RB401 R319 FL209 FL208 FL207 FL206 FL205 FB210 FB209 FB208 FB207 FB206 FB205 FB204 FB203 FB202 FB201 C501 C502 C503 D501 D502 D503 IC501 R501 R505 R506 R508 R510 R193 R190 R189 R187 R124 R172 R171 R615 R616 R617 R618 R619 R180 L101 IC209 R182 D102 R302 C252 C326 C325 R303 R308 C307 C311 C324 C316 L401 IC403 C253 IC204 FB214 FB213 FB212 C255 C254 C258 IC207 IC208 R370 R371 R310 C176 R203 R204 R205 R206 R207 R209 R210 R211 R212 R214 R312 R216 R217 R218 R219 R220 R221 R222 R223 R224 R227 R228 R146 R239 R241 IC101 R244 R1063 R247 R1062 R1061 R250 FB217 FB216 FB215 C248 R259 R262 C235 R263 R264 R265 R270 R271 R272 R274 R285 C103 R314 R315 R316 R317 R318 R296 R297 R298 R299 R300 R301 C104 C105 C106 C107 C108 C109 C110 C111 C115 C116 C117 C118 C179 C119 C120 C121 C122 C423 C422 C421 C419 R321 R326 R327 R328 R330 R331 R334 R366 R362 R361 R360 C322 C321 C320 R337 R338 R424 R342 R344 R345 R346 R348 R349 R350 R351 R352 C123 C249 C247 C246 C245 C244 C243 C241 C240 C239 C237 C236 R261 C125 C233 C232 C231 C128 C226 C130 C131 C132 C133 C217 C215 C214 C213 C212 C211 C210 C135 C136 C137 R1006 R1007 R1014 R1015 C207 C138 C205 R1027 R1029 C139 R1035 R1036 R356 C141 RB207 RB209 C144 RB211 C147 C150 C151 R192 R188 R186 R183 R179 R178 R156 R155 R153 R151 R150 R147 R145 R144 R140 R139 R138 R137 R136 R135 R134 R133 R132 R131 R130 R129 R128 R127 R126 R125 R1020 R123 R122 R120 R119 R118 R117 R116 R115 R110 R108 R101 R1019 Q104 Q102 Q103 L202 C158 L201 L108 L106 L104 L102 C163 C164 C166 C167 C112 C196 C190 C189 C187 C185 C184 C182 C174 R1038 R1043 R142 R641 R642 R215 R109 R325 R332 MB BOARD (SIDE B) 1-863-799- 11 A K K A K K A K K 3 1 2 1 3 2 1 10 20 11 E E A B C D E F G H 1 2 3 4 5 6 7 8 9 10 11 12 D102 B-8 D501 A-4 D502 A-4 D503 B-4 IC101 D-11 IC203 F-10 IC204 F-7 IC207 E-2 IC208 E-3 IC209 B-6 IC403 C-6 IC501 B-3 Q101 B-8 Q102 B-8 Q103 B-9 Q104 B-9 • Semiconductor Location Ref. No. Location w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DVP-CX995V 46 46 DVP-CX995V 7-8. SCHEMATIC DIAGRAM – MB Section (1/7) – • See page 68 for Waveforms. • See page 76 for IC Pin Function Description. R101 R102 R103 R104 R183 Q102 R186 Q103 IC104 R193 R105 R106 R107 R138 R143 R146 R153 C131 C138 C150 C106 C107 C108 C109 C110 C111 C119 R125 R123 R122 R121 R120 R119 C115 R197 R196 R175 R113 R114 R118 R1019 C118 C120 C114 R112 R111 C141 C147 C151 C163 C166 R179 R178 R173 Q105 C170 C175 C178 C172 R177 R174 R192 C174 C182 C196 C179 C177 C137 R169 R170 C167 R137 R134 R176 R181 R149 R152 R154 R157 R158 R159 R164 C171 C173 R141 C135 R194 C185 C186 C159 C104 C103 R1020 CN101 C102 R171 C127 C117 R126 R117 R110 R127 R172 C145 C132 R145 R139 R150 R151 Q104 C194 R130 R182 R124 R180 CN102 C126 C195 C142 C191 C158 C188 C112 D102 C105 C187 CN001 CN002 CN003 SL001 R132 R1002 C184 R185 R184 C176 R1028 Q101 C190 C189 100 100 100 100 10k 2SC4617FTLQ 10k 2SB1132-T100-QR STE6317ATXXY 1 100 100 100 10k 10k 0 6.8k 0.01 0.01 0.01 22p 22p 22p 22p 22p 22p 0.01 20k 510 510 510 510 510 0.01 10k 10k 10k 10k 10k 10k 10k 0.01 0.01 0.01 10k 10k 0.01 0.01 0.01 0.01 0.01 680 12k 2.2 KTA1504Y 18p 56p 1500p 7p 100 1k 10M 0.01 0.01 0.01 0.01 470p 0.01 0 0 0.01 10k 10k 10k 10k 47 47 47 47 47 47 47 47 6.3V 47 6.3V 10k 0.01 0 0.1 100 6.3V 22 6.3V 0.01 0.01 2.2 31P 100 6.3V 100k 22 6.3V 0.01 270 22 22 220 100k 22 6.3V 0.01 22 22 270 220 2SC4617FTLQ 22 6.3V 6.8k 1 1 1 5P 100 6.3V 22 6.3V 100 6.3V 100 6.3V 0.01 100 6.3V 0.01 1SS355 0.01 0.01 24P 9P 31P 10k 10k 0.01 4.7k 4.7k 0.01 100k 2SB1132-T100-QR 1000p 1000p B1 B2 B3 B4 B5 5V-A 1.8V-A AGND 1.8V-D B_ERROR XBCLK XPCLK XDATA B_WCLK B_V4 FE_CLK RFSACD XERROR 3.3V-A FE_RST BE_SCL BE_SDA FE_IRQ FCS+ FCS- TRK+ TRK- E F E F C D B A LD1 LD2 LD2 LD1 XPCLK XDATA XERROR B_V4 STEPA STEPB FACT TACT DVD/CD INLIM PD MUTE_DRV MUTE_SP DVD/CD INLIM B_WCLK B_ERROR XBCLK PD CD_LD DVD_LD DVD_LD CD_LD D C A B SP SPDIR B_ERROR B_WCLK XBCLK XPCLK XDATA B_V4 XERROR BE_SCL BE_SDA BE_SDA BE_SCL FE_IRQ FE_IRQ SP- SP+ SLA- SLB+ SLA+ SLB- FE_CLK FE_RST FE_CLK FE_RST D C RF GND VC VCC E A B F NC PD VR VCC SW(DVD/CD) GND LD(DVD) INLIM LD(CD) INLIM(POWER) FCS+ FCS- TRK+ TRK- SPINDLE+ SPINDLE- SLEDGEA- SLEDGEB- GND SLEDGEB+ SLEDGEA+ RF MON GND IOP IOP_5V RF MON(JIT) (1/7) NC B A F RF VC C D E PD VR SW N.C FCS+ FCS- TRK+ TRK- INLIM SPDL+ SPDL- B A F RF GND VC VCC C D E PD VR SW N.C FCS+ FCS- TRK+ TRK- VCC INLIM LD(DVD) LD(CD) INLIM(POWER) INLIM(POWER) LD(CD) LD(DVD) GND SLEDA- SLEDB- SLEDB+ SLEDA+ SLEDA+ SLEDB+ SLEDA- SLEDB- SPDL- SPDL+ NC NC NC GND(OPEN) GND(LD) GND(PD) VCC(PD) VCC(LD) Q101,102 AUTOMATIC POWER CONTROL (FOR DVD) AUTOMATIC POWER CONTROL (FOR CD) RF FILTER DVD INTERFACE Q103,104 L101 IDµH L102 47µH L108 IµH L106 IµH L103 47µH L104 10µH L105 2.2µH OPTICAL TRAVERSE UNIT (DBU-3) (Page 47) (Page 48) (Page 50) (Page 51) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DVP-CX995V 47 47 DVP-CX995V IC102 IC101(2/4) R187 R188 R189 R190 R108 R109 C164 C139 R156 IC101(1/4) C130 C144 R155 C123 C113 IC101(4/4) C121 R128 R136 R144 R135 IC101(3/4) C116 R148 C136 R147 C156 C155 C154 C153 R161 R162 R163 R160 C124 R168 R167 R166 R165 SL102 SL103 SL101 R142 R133 R131 C133 C128 C149 C146 IC103 C134 R129 R116 R115 C125 C122 C165 C129 R140 FAN8035L LMV324MT/NOPB 10k 22k 22k 4.7k 10k 10k 0.01 0.01 22k LMV324MT/NOPB 0.01 0.01 22k 0.01 0.01 LMV324MT/NOPB 0.22 30k 4.7k 4.7k 4.7k LMV324MT/NOPB 0.22 24k 1000p 27k 0.01 0.01 100p 100p 15k 56k 56k 22k 22 6.3V 33k 33k 10k 10k 6.8k 47k 47k 0.01 0.01 0.01 100 10V BA07FP-E2 47 6.3V 1k 10k 10k 0.01 0.01 47 16V 22 6.3V 4.7k B1 B2 B3 B4 B5 DGND 3.3V-D 5V-D PGND 12V-D FACT TACT STEPA STEPB MUTE_DRV MUTE_SP TRK- TRK+ FCS+ FCS- SPDIR SP- SP+ SLB- SLB+ SLA- SLA+ SP G O I (2/7) +7V REGULATOR TRACKING/FOCUS COIL DRIVE, SPINDLE/SLED MOTOR DRIVE REFERENCE VOLTAGE (4/4) 13 12 14 7 4 5 6 11 9 10 8 1 2 3 (1/4) CENTRE VOLTAGE LOW-PASS FILTER (2/4) (3/4) GENERATOR GENERATOR 7-9. SCHEMATIC DIAGRAM – MB Section (2/7) – • See page 69 for IC Block Diagrams. (Page 46) (Page 51) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DVP-CX995V 48 48 DVP-CX995V 7-10. SCHEMATIC DIAGRAM – MB Section (3/7) – • See page 68 for Waveforms. • See page 76 for IC Pin Function Description. R205 R225 R226 R227 R279 R280 R281 R285 R289 R206 R207 R208 R210 R218 R220 R222 R223 R1025 R204 R217 R1029 R238 R240 R1001 R202 R215 R1024 R277 R278 C245 FB211 C242 C249 C244 C246 R1006 C243 FB219 R1007 C223 R237 R245 R248 R251 R253 R255 R268 R269 R243 R246 R252 RB213 RB212 RB211 R249 R254 R257 R256 R229 R230 C217 R239 R241 C226 R244 R247 R250 C232 R296 R258 R266 C239 R1060 R270 R271 R1059 R273 R275 R276 RB205 RB206 R1003 R260 R297 C211 RB201 RB202 RB203 C214 R209 R212 R211 R214 C247 C208 C210 C254 C212 R216 R219 R221 R224 C213 R228 R1004 R1005 C215 C209 C207 C206 R203 R201 D202 R1014 FB214 C202 X201 C201 C203 FL203 FL201 R1015 R298 R301 R299 R262 R263 R300 R261 R265 C237 C235 R1038 R1035 R1043 RB210 RB208 RB215 RB216 L201 C259 IC205 R1027 FB212 C240 C241 R1036 FB213 C229 C238 R1034 R1033 R1023 R1022 IC201 R272 R236 R274 R233 R235 47 47 47 10k 47 47 47 2.7k 47 0 0 0 0 0 0 0 0 0 0 10k 0 47 47 47 150 0 22 10k 10k 0.01 0 22 6.3V 0.01 0.01 0.01 10k 0.01 0 10k 0.01 47 47 47 47 47 47 47 47 4.7k 4.7k 4.7k 47 47 47 4.7k 4.7k 47 4.7k 47 47 0.01 47 47 0.01 47 47 47 0.01 10k 47 47 0.01 47 75 75 47 47 47 47 47 47 10k 47 2.7k 0.01 47 47 47 0.01 10k 10k 10k 10k 0.01 22 6.3V 0.01 470p 0.01 10k 10k 10k 10k 0.01 10k 10k 10k 0.01 47 4V 0.01 47 4V 47 1M 1SS367 47 0 0.01 27MHz 4p 4p 47 10 10k 2.7k 1.8k 1.8k 10 10 10 10p 10p 10k 10k 10k 47 47 10 10 47 4V STE5588CVB 47 0 100p 100p 10k 0 0.01 0.01 0 0 0 0 SN74HCU04APWR 47 47 47 47 47 A1 A2 A3 A4 A5 A6 A7 A8 A9 BE_CS B_ERROR XBCLK XPCLK XDATA B_WCLK B_V4 FE_CLK DGND 3.3V-D 1.8V-D XERROR FE_RST BE_SCL BE_SDA BE_TXD BE_RXD FE_IRQ SA_SYS_CLK BE_BUSY TMODE_SW BE_RST B_V4 XERROR XPCLK XBCLK XDATA F_OE F_WE F_CE B_WCLK DATA1 DATA2 DATA3 DATA5 DATA6 DATA7 DATA8 DATA9 DATA11 DATA12 DATA13 I2S_SYNC_OUT I2S_WCK_OUT PCM_SCLK PCM_DATA0 SCLK LETTER SQUEEZE FJ_CE YC_CLKOUT PCM_DATA3 ADAC_CS SO SA_RW SA_WAIT SA_CS SPDIF PCM_LRCK B_ERROR B_WCLK XBCLK XPCLK XDATA B_V4 XERROR FE_RST BE_SDA BE_SCL BE_SCL BE_SDA BE_A_MUTE FE_IRQ FE_CLK FE_IRQ SA_IRQ H_SCL_BP H_SDA_BP H_INT_B +5V_CONT_B PCM_DATA1 PCM_DATA2 VIDEO_RST DATA0 DATA4 DATA10 DQ15 DQ14 DQ13 DQ12 DQ11 DQ10 SMI-CLK DQ9 DQ8 DQ7 DQ5 DQ6 DQ3 DQ4 DQ2 DQ1 DQ0 SMI-DQMU SMI-DQML SMI-WE SMI-CAS SMI-RAS SMI-CS0 AD13 AD12 AD11 AD10 AD0 AD1 AD3 AD2 AD9 AD8 AD7 AD6 AD5 AD4 I2S_BFLAG_OUT I2S_BCLK_OUT I2S_DATA_OUT YC7 YC6 YC5 YC3 YC2 YC1 YC4 YC0 FUR_RST FE_RST B_ERROR ADDR20 ADDR21 ADDR1 DATA14 DATA15 ADDR2 ADDR3 ADDR4 ADDR5 ADDR6 ADDR7 ADDR8 ADDR9 ADDR10 ADDR11 ADDR12 ADDR13 ADDR14 ADDR15 ADDR16 ADDR17 ADDR18 ADDR19 FE_CLK (3/7) OSC BUFFER CPU L203 10µH L202 1µH (Page 52) (Page 51) (Page 52) (Page 50) (Page 46) (Page 49) (Page 49) (Page 52) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DVP-CX995V 49 49 DVP-CX995V R213 R1039 R1040 R1041 R1042 FB220 FB221 R264 R1074 R1057 R1058 R1056 FL204 C219 R1047 R1048 R1049 R1050 R1055 R1051 R1052 R1053 R1054 C255 FB217 R1063 IC206 R1062 FB216 FB215 R1061 C248 RB209 RB207 C228 C225 C222 C221 C234 RB204 RB214 R242 C227 C224 C220 C218 R267 R234 R259 R232 R231 C233 C236 C231 C230 C216 C205 C204 FL202 CN205 IC204 R642 R619 R641 R615 R617 R616 R618 IC209 IC203 0 0 0 0 0 0 0 10 47 100 100 75 0.01 0.01 0 100 SN74LV08APWR 100 0 0 100 0.01 82 82 0.01 0.01 0.01 0.01 0.01 82 82 47k 0.01 0.01 0.01 47 4V 10k 10k 0 10 0 0.01 0.01 0.01 47 4V 0.01 0.01 47 4V 33P M29W320ET70N6E 0 0 0 0 0 0 0 SN74LV541APWR HY57V281620ETP -HDR A1 A2 A3 A4 A5 A6 A9 A7 A8 SPDIF PCM_LRCK PCM_DATA3 PCM_DATA2 PCM_DATA1 PCM_DATA0 PCM_SCLK ADAC_CS SO SCLK ADDR1 ADDR2 ADDR3 ADDR4 ADDR5 ADDR6 ADDR7 DATA0 DATA1 DATA2 DATA3 DATA4 DATA5 DATA6 DATA7 DATA8 DATA9 DATA10 DATA11 DATA12 DATA13 DATA14 DATA15 SA_CS SA_IRQ SA_WAIT SA_RW 3.3V-D DGND I2S_BFLAG_OUT I2S_SYNC_OUT I2S_WCK_OUT I2S_DATA_OUT I2S_BCLK_OUT BE_A_MUTE FUR_RST VMUTE V_OFF CIS_RXD CIS_TXD SACD_MCLK AUD_MCLK DQ8 DQ9 DQ10 DQ12 DQ13 DQ14 DQ7 DQ6 DQ5 DQ3 DQ2 DQ1 SMI-DQMU SMI-CLK AD11 SMI-DQML SMI-WE SMI-CAS SMI-RAS SMI-CS0 AD9 AD8 AD7 AD6 AD5 AD4 AD12 AD13 AD10 AD0 AD1 AD2 AD3 SPDIF PCM_LRCK PCM_DATA3 PCM_DATA2 PCM_DATA1 PCM_DATA0 PCM_SCLK SO SCLK ADAC_CS BE_A_MUTE H_SDA_BP H_SCL_BP BE_SDA BE_SCL SACD_MCLK AUD_MCLK PCM_LRCK PCM_SCLK HDMI_MCLK YC_CLKOUT YC0 YC1 YC2 YC3 YC4 YC5 YC6 YC7 DQ0 DQ4 DQ15 DQ11 ADDR17 DATA15 DATA7 DATA14 DATA6 DATA13 DATA5 DATA12 DATA4 DATA11 DATA3 DATA10 DATA2 DATA9 DATA1 DATA8 DATA0 F_OE F_CE ADDR1 ADDR17 DATA15 DATA7 DATA14 DATA6 DATA13 DATA5 DATA12 DATA4 DATA11 DATA3 DATA10 DATA2 DATA9 DATA1 DATA8 DATA0 F_OE FJ_CE ADDR1 ADDR16 ADDR15 ADDR14 ADDR13 ADDR12 ADDR11 ADDR10 ADDR9 ADDR20 ADDR21 F_WE ADDR19 ADDR18 ADDR8 ADDR7 ADDR6 ADDR5 ADDR4 ADDR3 ADDR2 ADDR16 ADDR15 ADDR14 ADDR13 ADDR12 ADDR11 ADDR10 ADDR9 ADDR20 ADDR21 F_WE ADDR19 ADDR18 ADDR8 ADDR7 ADDR6 ADDR5 ADDR4 ADDR3 ADDR2 ADDR1 ADDR2 ADDR3 ADDR4 ADDR5 ADDR6 ADDR7 DATA0 DATA1 DATA2 DATA3 DATA4 DATA5 DATA6 DATA7 DATA9 DATA10 DATA11 DATA12 DATA13 DATA14 DATA15 SA_CS SA_IRQ SA_WAIT SA_RW I2S_BFLAG_OUT I2S_SYNC_OUT I2S_WCK_OUT I2S_DATA_OUT I2S_BCLK_OUT FUR_RST DATA8 LETTER SQUEEZE VIDEO_RST +5V_CONT_B H_INT_B SACD_MCLK AUD_MCLK HDMI_MCLK CIS_TXD CIS_RXD VMUTE V_OFF GND YC7 YC6 YC5 YC4 YC3 YC2 YC1 YC0 GND YC_CLKOUT GND VIDEO_RST BE_SCL BE_SDA HDMI_SCL HDMI_SDA SD0 SD1 SD2 SD3 PCM_MCLK BCK LRCK HDMI_INT +5V_CONT GND LETTER SQUEEZE (4/7) OSC BUFFER FLASH MEMORY FLASH MEMORY BUFFER SD-RAM IC202 M29W320ET70N6E -M005 7-11. SCHEMATIC DIAGRAM – MB Section (4/7) – • See page 69 for IC Block Diagrams. (Page 48) (Page 51) (Page 50) (Page 50) (Page 50) (Page 51) (Page 52) (Page 54) (Page 48) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DVP-CX995V 50 50 DVP-CX995V 7-12. SCHEMATIC DIAGRAM – MB Section (5/7) – • See page 69 for IC Block Diagrams. • See page 76 for IC Pin Function Description. R421 L401 10µ FL401 C415 C417 C416 C418 C412 C411 C409 C410 C429 R414 C428 C405 C404 C402 C403 C422 C421 C420 C419 R424 C423 RB403 RB404 C425 C424 R425 C426 R407 FL402 C414 IC403 R428 R417 R429 R415 R613 CL246 RB401 RB402 R418 IC401 C413 47 0.01 0.01 0.01 0.01 0.01 0.01 0.01 0.1 0.01 2200P 47 4V 0.01 0.01 47 4V 47 4V 0.01 0.01 0.01 0.01 1k 0.01 68 68 0.01 0.01 10k 0.001 100 0.01 HY57V641620ETP -HDR 10k 10k 0 12k 0 68 68 0 SAA7893HL 0.01 DSD_PCM0 DSD_PCM1 DSD_PCM2 DSD_PCM3 DSD_PCM4 DSD_PCM5 DSD_PCM8 DSD_PCM11 AGND RFSACD DGND DATA11 ADDR1 ADDR2 ADDR3 ADDR4 ADDR5 ADDR6 ADDR7 DATA0 DATA1 DATA2 DATA3 DATA4 DATA5 DATA6 DATA7 DATA8 DATA9 DATA10 DATA12 DATA13 DATA14 DATA15 SA_CS SA_IRQ SA_WAIT SA_RW I2S_BFLAG_OUT I2S_SYNC_OUT I2S_WCK_OUT I2S_DATA_OUT I2S_BCLK_OUT SA_SYS_CLK FUR_RST 1.8V-A 1.8V-D 3.3V-D SACD_MCLK DSD_PCM9 FUR_DQ1 FUR_DQ2 FUR_DQ3 FUR_DQ5 FUR_DQ6 FUR_DQ7 FUR_DQ8 FUR_DQ9 FUR_DQ10 FUR_DQ12 FUR_DQ13 FUR_DQ14 FUR_ADDR0 FUR_ADDR1 FUR_ADDR2 FUR_ADDR3 FUR_ADDR4 FUR_ADDR5 FUR_ADDR6 FUR_ADDR7 FUR_ADDR8 FUR_ADDR9 FUR_ADDR10 FUR_ADDR11 FUR_ADDR12 FUR_ADDR13 FUR_CLK FUR_NUDQM FUR_NRAS FUR_NCAS FUR_NWE FUR_NLDQM FUR_CLK FUR_NUDQM FUR_NLDQM FUR_NCAS FUR_NRAS FUR_NWE FUR_DQ0 FUR_DQ1 FUR_DQ2 FUR_DQ3 FUR_DQ4 FUR_DQ5 FUR_DQ6 FUR_DQ7 FUR_DQ8 FUR_DQ9 FUR_DQ10 FUR_DQ11 FUR_DQ12 FUR_DQ13 FUR_DQ14 FUR_DQ15 DATA0 DATA1 DATA2 DATA3 DATA4 DATA5 DATA6 DATA7 DATA8 DATA9 DATA10 DATA11 DATA12 DATA13 DATA14 DATA15 ADDR1 ADDR2 ADDR3 ADDR4 ADDR5 ADDR6 ADDR7 FUR_ADDR0 FUR_ADDR1 FUR_ADDR2 FUR_ADDR3 FUR_ADDR4 FUR_ADDR5 FUR_ADDR6 FUR_ADDR7 FUR_ADDR8 FUR_ADDR9 FUR_ADDR10 FUR_ADDR11 FUR_ADDR12 FUR_ADDR13 DSD_PCM0 DSD_PCM1 DSD_PCM2 DSD_PCM3 DSD_PCM4 DSD_PCM5 DSD_PCM8 DSD_PCM11 SA_CS SA_RW SA_WAIT SA_IRQ ADDR1 ADDR2 ADDR3 ADDR4 ADDR5 ADDR6 ADDR7 DATA0 DATA1 DATA2 DATA3 DATA4 DATA5 DATA6 DATA7 DATA8 DATA9 DATA10 DATA11 DATA12 DATA13 DATA14 DATA15 SA_CS SA_IRQ SA_WAIT SA_RW DSD_PCM9 FUR_DQ4 FUR_DQ0 FUR_DQ15 FUR_DQ11 DSD_PCM0 DSD_PCM1 DSD_PCM2 DSD_PCM3 DSD_PCM4 DSD_PCM5 DSD_PCM8 DSD_PCM9 DSD_PCM11 FUR_RST FUR_RST (5/7) SACD MEDIA PLAYER SD-RAM (Page 51) (Page 51) (Page 49) (Page 49) (Page 51) (Page 46) (Page 48) (Page 49) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DVP-CX995V 51 51 DVP-CX995V C502 R505 R506 C501 R510 R508 D502 D501 D503 CN501 C252 C253 C257 C258 FB207 FB205 FB209 FL208 FB206 FB204 FB203 FB202 FB201 FL205 FL206 FL209 FB210 FB208 IC208 C264 C265 C262 C266 C250 C251 C263 CN203 C507 C503 C505 R501 FL207 IC501 0.1 10 0 0.001 0 0 DAP202K-T-146 DAP202K-T-146 DAP202K-T-146 29P 0.1 0.1 0.1 0.1 100 6.3V 47 16V 100 6.3V 47 4V 220 4V 100 6.3V 220 4V 9P 100 6.3V 0.1 100 6.3V 0 AK4358VQ DSD_PCM0 DSD_PCM1 DSD_PCM2 DSD_PCM3 DSD_PCM4 DSD_PCM5 DSD_PCM8 ADAC_CS SO SCLK DSD_PCM11 PCM_LRCK PCM_SCLK BE_A_MUTE AMUTE BE_RST AUD_MCLK DSD_PCM9 SPDIF PCM_DATA3 PCM_DATA1 PCM_DATA2 PCM_DATA0 12V-D PGND 3.3V-EVER P_CONT 5V-A 3.3V-A 1.8V-A 1.8V-D AGND 1.8V-D 3.3V-D DGND 1.8V-D DGND 3.3V-D 3.3V-D DGND 1.8V-A AGND 5V-D 5V-D DGND 3.3V-D 3.3V-D DGND DZF23 DZFR1 DZFL1 LOUT1+ LOUT1- ROUT1+ ROUT1- LOUT2+ LOUT2- ROUT2+ ROUT2- LOUT3+ LOUT3- ROUT3+ ROUT3- DZF23 LOUT2- LOUT2+ ROUT2+ ROUT2- LOUT1- LOUT1+ ROUT1+ ROUT1- ART- ART+ LOUT3- LOUT3+ ROUT3+ ROUT3- ALT- ALT+ ART+ ART- DZFL1 DZFR1 ALT+ ALT- GND SPDIF A+5V ART- MUTE_23 ART+ MUTE_L ALT+ MUTE_R ALT- LOUT2- LOUT2+ LOUT1+ LOUT1- ROUT2- ROUT2+ A_GND ROUT1+ ROUT1- LOUT3- ROUT3+ ROUT3- LOUT3+ A_GND A_GND AGND AMUTE S_GND CONTROL_S SW+5V GND GND(M) GND EVER+3.3V PCONT SW+12V(M) SW+4.5V SW+3.3V (6/7) D/A CONVERTER +1.8V REGULATOR +3.3V REGULATOR G O I O G I IC207 µPC291B-E1 µPC2933-E1 7-13. SCHEMATIC DIAGRAM – MB Section (6/7) – • See page 69 for IC Block Diagrams. (Page 52) (Page 52) (Page 49) (Page 50) (Page 46) (Page 48) (Page 50) (Page 49) (Page 50) (Page 52) (Page 47) (Page 52) (Page 56) (Page 52) (Page 57) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DVP-CX995V 52 52 DVP-CX995V R310 R312 R344 IC302 IC305 IC306 R303 R342 R349 SL301 R371 R370 R369 SL302 R337 R338 R348 R346 R345 R350 R319 R302 R304 R352 R351 R361 R360 R353 R354 C322 C321 C316 C320 C328 C327 C326 Q304 D101 R308 R328 R325 R326 C310 R334 Q303 R332 R331 R314 R321 C307 C309 R330 X301 C315 C313 C325 C324 C311 R327 C301 C319 R347 C314 R322 R333 R341 R381 R316 Q302 Q301 R306 R307 R311 R309 R305 R368 R372 CN305 CN304 CN303 CN301 CN307 R317 C317 C305 R315 R318 D301 R356 R362 R313 R366 C323 Q305 Q306 R358 RV301 Q307 PST9127NL PST9127NL S-80827CNUA-B8MT 0 100 100 0 10k 0 10k 10k 0 10k 10k 10k 10k 10k 10k 0 0 0 33 120 10k 10k 10k 10k 0.01 0.01 0.01 0.01 0.01 0.01 0.01 DTA123EKA-T146 1SS367 10k 10k 100 100 0.01 10k DTC114EKA-T146 10k 10k 10k 10k 1 0.01 10k 5MHz 47 4V 0.01 0.01 0.01 1000p 100k 0.01 0.01 10k 0.001 0 0 470k 100 47k 2SC2712-YG -TE85L 2SC2712-YG -TE85L 22 22 22 22 22 0 0 10P 9P 25P 3P 4P 100k 0.1 100p 47k 10k 1SS355 0 10k 22 10k 0.01 DTA144EKA-T146 DTA144EKA-T146 3.3k 22k DTC114EKA-T146 DGND 3.3V-EVER 5V-D BE_TXD BE_RXD BE_CS 3.3V-D BE_RST BE_BUSY P_CONT AMUTE VMUTE V_OFF CIS_TXD CIS_RXD TMODE_SW BE_RST KEY0 KEY1 KEY2 KEY3 FLDSDATA FLDSCLK FLDRST FLDCS KEY0 KEY1 KBCOUT KBDOUT KEY4 IFRST IFRST TSENS3 DRM+ DRM- LDM+ LDM- DRM- DRM+ LDM- LDM+ TSENS1 TSENS2 TSENS3 TSENS4 IR TSENS1 BE_TXD BE_RXD TBM+ TBM- BE_TXD BE_RXD 3.3V-D TBM- TBM+ DSENS_IN TSENS4 TSENS2 DSENS_IN BE_CS BE_CS LD_SW DR_SW LD_SW DR_SW BE_RST BE_BUSY BE_BUSY JOG_B JOG_A KBD_IN KBC_IN P_CONT AMUTE VMUTE P_CONT AMUTE VMUTE V_OFF V_OFF CIS_RXD CIS_TXD CIS_RXD LED2 LED0 LED5 LED1 LED6 FLDRST FLDCS IR FLDSCLK FLDSDATA LED4 KBCOUT LED3 KBC_IN KEY1 KBDOUT KEY3 KBD_IN KEY4 JOG_B JOG_A KEY2 KEY0 DIMM TMODE_SW TMODE_SW BE_RST LED0 LED1 LED2 LED3 LED4 DIMM LED5 LED6 CIS_TXD CIS_RXD DSENS TSENS1 TSENS2 TSENS3 TSENS4 GND S+5V S+5V LED DRM- DRM+ LDM- LDM+ FLDRST FLDCS GND KEY1 KEY3 LED0 LED1 LED2 LED3 LED4 LED5 LED6 KEY4 KBDOUT KBCOUT GND DSENS_OUT HH_OUT GND IR TBM- TBM+ JOG_A JOG_B KEY2 KEY0 TXD RXD GND +3.3V GND GND LOAD_SW DOOR_SW FLDCLK FLDDATA KBCIN KBDIN (FOR ADJUSTMENT) NC (7/7) WAKE-UP SWITCH WAKE-UP SWITCH RESET SIGNAL Q301,302 WAKE-UP SWITCH INVERTER INVERTER LED DRIVE Q303,304 LEVEL SHIFT GENERATOR SYSTEM CONTROLLER IC304 µPD703260-YGF -S30-JBT-A 7-14. SCHEMATIC DIAGRAM – MB Section (7/7) – • See page 68 for Waveforms. • See page 76 for IC Pin Function Description. (Page 51) (Page 51) (Page 48) (Page 48) (Page 48) (Page 51) (Page 49) (Page 51) (Page 63) (Page 61) (Page 67) (Page 51) (Page 65) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DVP-CX995V 53 53 DVP-CX995V R405 R406 R407 R408 IC400 R479 R478 R477 R476 RB419 RB420 RB421 RB422 RB423 RB424 C462 C463 C464 C467 C468 C469 C470 C471 C472 C453 C407 C410 C415 C423 C430 C431 C433 C434 C435 C436 C437 C439 C438 RB407 RB406 RB405 RB404 RB403 RB402 RB401 C443 RB411 RB412 FB400 C444 RB413 RB414 C426 C429 C466 C427 C465 R410 R409 R480 C404 R422 R421 C459 C406 C441 R481 C440 C408 C461 R412 R413 R414 R415 R416 R417 R418 R419 RB408 RB409 RB410 C445 C409 C403 C402 C401 RB428 RB427 C451 C419 C424 C457 C458 C452 C446 C414 C450 C456 R459 C449 C454 C448 C425 C455 C420 C447 C411 C413 C416 C418 C421 R463 C428 C432 C422 RB429 RB430 C460 C405 R455 RB426 RB425 C417 C412 IC401 R440 R451 IC402 0 0 0 0 TK11118CSCL-G 47 47 47 47 47 47 47 47 47 47 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1 470p 0.01 0.01 0.01 0.01 0.1 0.01 0.01 0.01 0.01 0.01 0.01 0.01 0.01 22 22 22 22 22 22 22 0.01 47 47 0 0.01 47 47 0.01 0.01 0.1 0.01 0.1 100 0 3.3k 0.001 330 330 0.1 0.01 0.033 820 0.33 0.01 0.1 330 330 330 330 330 330 330 330 47 47 47 100 6.3V 22 0.1 0.1 100 6.3V 47 47 470p 0.1 0.1 0.01 0.01 470p 47 4V 0.1 0.01 470p 0 470p 0.01 470p 0.1 0.01 0.1 0.01 0.01 0.01 0.01 0.01 0.01 100 0.01 0.01 0.01 330 330 0.1 0.01 0 47 47 0.01 0.01 CXD9866R 100 0 HY57V1616110ETP -7TD A1 A2 A3 A4 A5 A6 A7 B1 B2 B3 B5 B4 B6 B9 B10 B11 B12 3.3V-V CBCR9 CBCR8 CBCR7 CBCR6 CBCR5 CBCR4 CBCR3 CBCR2 CBCR1 CBCR0 Y6 Y5 Y4 Y2 Y1 Y0 CBCR0 CBCR1 CBCR2 CBCR4 CBCR5 CBCR6 B0 B1 B2 B4 B5 B6 A9 A11 A8 A10 A7 A0 A6 A1 A5 A2 A4 A3 D7 D8 D6 D9 D5 D10 D4 D11 D12 D2 D13 D1 D14 D0 D15 D3 A4 A5 A6 A7 A8 A9 WE CAS DQM RAS DQM YC0 YC1 YC2 YC3 YC4 YC5 YC6 YC7 D8 D9 D10 D11 D12 D13 D14 D15 D0 D1 D2 D4 D5 D6 DQM WE CAS RAS A11 A10 A0 A1 A2 A3 CBCR7 CBCR3 Y7 Y3 B7 B3 PO6 PO5 PO4 PO3 PO2 PO1 PO0 PO7 Y7 Y6 Y5 Y4 Y3 Y2 Y1 Y0 Y9 Y8 D7 D3 (1/5) +1.8V REGULATOR INTERLACE/PROGRESSIVE CONVERTER SD-RAM 7-15. SCHEMATIC DIAGRAM – AV Board (1/5) – • See page 69 for IC Block Diagrams. • See page 76 for IC Pin Function Description. (Page 54) (Page 54) (Page 55) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DVP-CX995V 54 54 DVP-CX995V R530 R531 R532 R533 R534 R535 C519 IC501 R411 C512 R502 R512 R511 R509 C502 C504 R520 R522 C510 C509 R521 C508 C511 R519 C507 C513 R524 R525 R526 R527 R528 R529 C515 C516 R537 C517 C518 C514 R403 R523 CN400 C506 C503 C501 C500 C505 IC502 IC500 R606 R604 RV500 RV501 RB415 RB416 0 0 0 0 0 0 100 6.3V TK11125CSCL-G 0 0.22 0 0 0 0 0.22 10 10k 1k 0.1 0.1 1k 820p 100 6.3V 680 0.0039 0.001 300 300 300 300 300 300 0.01 0.1 0 0.01 0.1 0.22 100 100 33P 0.22 100 6.3V 0.22 0.22 10 ADV7300KST 0 0 1k 1k 0 0 C1 C2 C3 B1 B2 B3 B4 B5 C4 C5 C6 B6 B9 B10 B11 B12 VMUTE 3.3V-V CR/B CB/R Y/G Y C V SW+5V SQUEEZE A-GND CBCR3 CBCR4 CBCR5 CBCR6 CBCR7 CBCR8 CBCR9 BCK LRCK SD0 SD1 SD2 SD3 PO7 PO6 PO5 PO4 PO3 PO2 PO1 PO0 Y0 Y1 Y2 Y3 Y4 Y5 Y6 Y7 Y8 Y9 CBCR0 CBCR1 CBCR2 YC7 YC6 YC5 YC4 YC3 YC2 YC1 YC0 CIS_TXD CIS_RXD VMUTE V_OFF GND YC7 YC6 YC5 YC4 YC3 YC2 YC1 YC0 GND YC_CLKOUT GND VIDEO_RST BE_SCL BE_SDA HDMI_SCL HDMI_SDA SD0 SD1 SD2 SD3 PCM_MCLK BCK LRCK HDMI_INT +5V_CONT GND LETTER SQUEEZE (2/5) +2.5V REGULATOR +3.3V REGULATOR G O I VIDEO D/A CONVERTER µPC2933T-E2 7-16. SCHEMATIC DIAGRAM – AV Board (2/5) – • See page 68 for Waveforms. • See page 69 for IC Block Diagrams. (Page 53) (Page 55) (Page 55) (Page 49) (Page 57) (Page 53) (Page 57) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DVP-CX995V 55 55 DVP-CX995V IC601 IC604 R629 C638 R617 C625 C605 C606 C607 C608 C637 C635 C634 D601 D603 D604 D605 D606 D607 D608 D602 R618 R619 C632 R615 R616 C629 C627 C626 R668 R667 R613 R612 C610 C613 C614 FB601 C612 C624 FB604 FB600 R614 R607 R609 R602 R601 R600 C601 C600 C609 C620 C622 C621 C603 C602 R611 C617 C618 R632 IC605 C636 C616 C619 C611 FB602 C615 RB603 RB604 RB602 RB601 C623 FB603 C631 C630 C628 C633 IC600 IC602 IC603 J600 C604 TK11133CSCL-G TK11118CSCL-G 0 47 6.3V 0 22 6.3V 0.1 0.1 0.1 0.001 0.22 0.01 0.1 PGB1010603NR PGB1010603NR PGB1010603NR PGB1010603NR PGB1010603NR PGB1010603NR PGB1010603NR PGB1010603NR 0 0 0.22 4.7k 47k 0.01 0.1 0.1 1.8k 1.8k 5.1 470 10 0.1 0.001 0.1 0.1 10k 4.7k 4.7k 100 100 100 0.1 0.1 22 0.1 22 22 0.1 0.1 0 0.1 0.1 0 SSM6N15FU 0.001 0.1 0.001 10 0.1 10 10 10 10 0.1 47 4V 0.1 0.22 0.1 SII9030 SN74LVC1G08DCKR TK11150CSCL-G 19P 0.1 A1 A2 A3 A4 A5 A6 A7 C1 C2 C3 C4 C5 C6 DGND SW+5V SPDIF SW+12V Y7 Y6 Y5 Y4 Y3 Y2 Y1 Y0 CBCR0 CBCR1 CBCR2 CBCR3 CBCR4 CBCR5 CBCR6 CBCR7 B0 B1 B2 B3 B4 B5 B6 B7 BCK LRCK SD0 SD1 SD2 SD3 DATA2+ DATA2- DATA1+ DATA2 SHIELD DATA1 SHIELD DATA1- DATA0+ DATA0 SHIELD DATA0- CLOCK+ CLOCK SHIELD CLOCK- CEC RESERVE(N.C.) DCC/CEC GND +5V POWER HOT PLUG DET SCL(5V) SDA(5V) (3/5) HDMI TRANSMITTER +1.8V REGULATOR +3.3V REGULATOR LEVEL SHIFT LEVEL SHIFT +5V REGULATOR HDMI OUT 7-17. SCHEMATIC DIAGRAM – AV Board (3/5) – • See page 68 for Waveforms. • See page 69 for IC Block Diagrams. (Page 54) (Page 53) (Page 56) (Page 54) (Page 57) (Page 57) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DVP-CX995V 56 56 DVP-CX995V Q302 Q305 C344 R213 R221 R322 R345 R356 J201 R207 C204 C202 R206 R208 R205 C203 R202 R201 R214 C213 R216 C212 R217 R215 C211 C301 C302 C215 R220 R210 R209 C217 C207 R218 R211 R212 C221 R222 R224 R223 C201 R204 R203 R233 R231 C231 R234 R232 C223 R226 R236 C232 C233 R235 R237 R238 R230 C227 C235 R240 C205 C225 C241 R243 R244 R242 R241 C243 C244 R247 R248 R228 R227 C224 C222 R225 R219 R301 R302 Q202 Q201 R229 R239 C237 R303 R304 Q204 C214 C234 C251 R254 R252 R251 R253 R246 C242 R245 C252 C245 R256 R255 C253 R257 R258 C254 C310 C255 R250 C247 C257 Q205 R305 R260 Q206 R306 IC202 IC203 C309 R259 R249 C261 R262 R263 R264 C263 R266 R267 R268 C264 IC204 C271 R279 R280 R271 R265 C262 C272 R274 R273 C273 R275 C274 R276 C265 R270 C267 R269 C313 C314 R278 Q208 R336 R334 R333 C323 Q307 R324 Q309 Q308 R323 C322 Q306 R314 C321 R313 R312 R307 R308 Q304 R311 R331 R321 R335 R332 R325 R315 D301 R326 R283 R281 R284 R282 R285 R286 R288 R289 R290 R287 C351 Q352 C353 R355 Q353 D351 R359 C355 C356 R342 C342 R341 C341 R343 R344 R346 CN306 R357 Q303 R316 R261 R272 Q207 C277 R277 C275 C306 C305 Q203 IC201 C354 R362 C357 C358 R358 IC302 Q310 C324 Q301 R354 Q351 C352 R351 R352 IC301 DTC124TKA-T146 DTC124TKA-T146 47 16V 820 820 10k 68 5.6k 6P 820 330p 330p 820 2.2k 2.2k 0.0047 1k 820 1k 0.0047 820 330p 820 2.2k 0.0039 47 25V 47 25V 47 16V 470 470 47k 0.00022 0.00022 2.2k 820 1k 0.0039 1k 1k 820 0.0039 1k 820 820 820 0.0039 1k 1k 0.0047 820 820 330p 0.0047 2.2k 820 2.2k 470 0.00022 47 16V 470 47 16V 47 16V 0.0039 820 1k 1k 820 0.0047 330p 820 2.2k 2.2k 820 330p 330p 2.2k 47k 3.3k 3.3k 2SD1938(F)-T(TX) 2SD1938(F)-T(TX) 47k 47k 0.00022 3.3k 3.3k 2SD1938(F)-T(TX) 330p 330p 0.0039 1k 1k 820 820 820 330p 2.2k 330p 47 16V 820 2.2k 0.0047 820 2.2k 330p 47 25V 47 16V 470 0.00022 0.00022 2SD1938(F)-T(TX) 3.3k 470 2SD1938(F)-T(TX) 3.3k NJM4558M-TE2 NJM4558M-TE2 47 25V 47k 47k 0.0039 1k 820 1k 0.0047 820 820 2.2k 330p NJM4558M-TE2 0.0039 820 820 1k 2.2k 330p 330p 820 2.2k 0.0047 820 330p 2.2k 47 16V 470 0.00022 47k 47 25V 47 25V 470 2SD1938(F)-T(TX) 100k 10k 47k 1 50V DTC144EKA-T146 10k 2SB709A-QRS-TX DTC124TKA-T146 47k 1 50V 2SB709A-QRS-TX 10k 1 50V 47k 10k 3.3k 3.3k DTC144EKA-T146 4.7k 4.7k 4.7k 10k 10k 10k 10k DAN202K-T-146 100k 100 100 100 100 100 100 100 100 100 100 47 25V 2SC2712-YG-TE85L 330 6.3V 100k 2SB710A-RTX 1SS355TE-17 0 47 25V 0.01 1k 47 16V 1k 47 16V 1k 220 10k 29P 10k 2SB709A-QRS-TX 100k 820 1k 2SD1938(F)-T(TX) 0.00022 47k 47 16V 47 25V 47 25V 2SD1938(F)-T(TX) NJM4558M-TE2 47 25V 0 0.1 47 16V 0 NJM78M05DL1A-TE1 2SC2712-YG-TE85L 1000 16V DTC144EKA-T146 100k 2SB709A-QRS-TX 47 25V 10k 470 2L 1L P_GND 1R 2R D_GND MUTE3.3V SPDIF EVER+12V SW-12V SW-12V_VIDEO ALT- ALT+ ART+ ART- LOUT3- LOUT3+ ROUT3+ ROUT3- ROUT2+ ROUT2- LOUT2- LOUT2+ LOUT1+ LOUT1- ROUT1- ROUT1+ ALT- ALT+ ART+ ART- LOUT1- LOUT1+ ROUT1+ ROUT1- LOUT2+ LOUT2- ROUT2+ ROUT2- LOUT3- LOUT3+ ROUT3+ ROUT3- MUTE_23 MUTE_L MUTE_R A_MUTE A_GND LOUT3- LOUT3+ ROUT3- ROUT3+ A_GND LOUT2- LOUT2+ ROUT2+ ROUT2- A_GND LOUT1- LOUT1+ ROUT1+ ROUT1- A+5V A_GND D_GND SPDIF S_GND CONTROL_S ALT- ALT+ ART+ ART- (4/5) Q301-309 MUTING CONTROL Q352,353 B+ SWITCH B- SWITCH +5V REGULATOR LINE AMP LINE AMP LINE AMP LINE AMP Q201-208 MUTING LEVEL SHIFT L L R R CENTER WOOFER FRONT REAR 5.1CH OUTPUT OPTICAL COAXIAL PCM/DTS/ DOLBY DIGITAL DIGITAL OUT VCC VEE VCC VEE VCC VEE VCC VEE L351 100mH 7-18. SCHEMATIC DIAGRAM – AV Board (4/5) – (Page 51) (Page 55) (Page 57) (Page 57) (Page 57) (Page 57) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DVP-CX995V 57 57 DVP-CX995V IC101 R110 C102 R132 D103 D104 R119 R118 R117 R116 R115 R114 R113 R112 R111 C109 C103 C105 IC102 C106 D101 R129 R1016 D102 C107 C108 C101 C382 R383 C371 C372 C373 C380 C374 C375 C384 R374 Q371 R377 R376 R375 Q372 C377 C381 C383 Q374 R382 R378 R379 C385 R380 C386 Q373 D371 R373 CN302 CN303 CN304 C317 C318 CN301 R103 G202 G201 C104 D106 D105 C379 C378 C376 Q104 Q103 J101 J103 J102 R101 PS371 PS372 JL371 JL373 JL376 JL378 JL382 JL381 JL383 NJM79M05DL1A (TE2) 10k 47 16V 0 HZM6.8ZWA1TL HZM6.8ZWA1TL 68 68 68 68 68 68 68 68 68 0.1 47 16V 0.047 LA73053-TLM-E 47 16V 1SR154-400TE-25 0 10k 1SR154-400TE-25 0.1 47 16V 0.1 0.01 47k 0.01 100 10V 0.01 0.01 0.01 100 25V 0.01 10k 2SD1766FT100QR 3.3k 3.3k 3.3k DTA114EKA-T146 0.01 100 25V 0.01 2SB709A-QRS-TX 4.7k 10k 1k 100 10V 33k 470p 2SC2712-YG-TE85L DAP202K-T-146 0 9P 3P 5P 0.1 0.1 14P 0 47 16V HZM6.8ZWA1TL HZM6.8ZWA1TL 0.01 100 10V 100 10V DTA124EKA-T146 DTC114YKA-T146 (AC IN) 6P 3P 0 CR/B CB/R Y/G Y C V VMUTE 2L 1L P_GND 2R 1R SW+5V D_GND SQUEEZE A-GND SW-12V_VIDEO SW-12V EVER+12V SW+5V MUTE3.3V SW+12V DGND GND(M) SW+12V(M) GND GND SW+5V E+3.3V P_CONT GND(M) SW+12V(M) SW-12V(M) SW-12V(FL) SW-GND SW+5V GND EVER+12V SW+5V EVER+3.3V GND GND SW+4.5V SW+4.5V SW+12V SW+12V GND(M) GND(M) SW-12V EVER-12V P-CONT SW+4.5V SW+3.3V (5/5) (CHASSIS) (CHASSIS) EVER+3.3V VIDEO AMP Q103,104 WIDE ON/OFF SWITCH -5V REGULATOR +3.3V REGULATOR G I O Q371,372 B- SWITCH Q373,374 B+ SWITCH PB/CB PR/CR Y COMPONENT VIDEO OUT 1 2 S VIDEO OUT 2 1 L R VIDEO LINE OUT SWITCHING REGULATOR AUDIO IC371 µPC2933T-EI L102 22µH L101 22µH 7-19. SCHEMATIC DIAGRAM – AV Board (5/5) – • See page 68 for Waveforms. • See page 69 for IC Block Diagrams. (Page 54) (Page 54) (Page 56) (Page 55) (Page 55) (Page 56) (Page 56) (Page 51) (Page 63) (Page 56) (Page 65) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DVP-CX995V 58 58 DVP-CX995V 7-20. PRINTED WIRING BOARD – AV Board (Component Side) – • See page 42 for Circuit Boards Location. : Uses unleaded solder. C450 CN400 D106 R421 IC102 C503 C441 C440 C429 C426 C414 RB413 C404 C403 C402 C445 RB405 R535 R534 R533 R532 R531 R530 R529 R528 R527 R526 R525 R524 R520 C504 C505 R481 R480 R479 RB402 RB404 R476 RB416 RB412 RB414 RB407 C409 RB426 RB401 RB425 RB403 RB415 R478 RB429 RB408 RB409 RB410 RB411 RB430 R375 RB406 R403 C513 C509 C510 R523 C514 C515 C516 C519 C622 C609 C616 C456 L351 C624 C626 C627 C628 C630 C631 C634 C635 C637 C638 CN306 FB600 FB604 IC400 C401 IC402 IC500 C102 IC501 IC601 C511 D104 R113 R112 R111 IC604 L102 L101 D105 C108 D103 D102 D101 C109 C106 C103 C104 IC371 R362 R358 R357 R356 R355 R354 R352 R336 R335 R334 R333 R332 R331 R326 R325 R324 R323 R322 R321 R316 R315 R314 R313 R312 R311 R274 R273 R266 R265 R256 R255 Q372 Q374 R246 R245 R376 R377 RB424 R378 R379 R382 R383 R236 R226 R225 R206 R216 R215 R351 R205 Q353 Q352 Q351 Q310 Q309 Q308 Q307 Q306 Q305 Q304 Q303 Q302 Q301 C383 IC302 C384 D351 D301 C357 C356 D371 IC401 R235 C621 RB421 RB422 C636 IC603 C633 R616 FB603 C623 IC600 C611 R601 R602 C610 R604 R600 RB419 C446 R463 RB420 RB423 RB427 RB601 RB602 RB603 RB604 R606 R607 R668 R667 C625 IC602 J600 RB428 R609 IC605 A B C D E F G H I J 1 2 3 4 5 6 7 8 9 10 11 12 13 E E E E E E E E E E E E E E E 1 1 3 6 4 16 17 32 64 49 48 33 1 3 6 4 1 3 5 4 1 3 6 4 1 1 19 3 5 4 1 3 6 4 1 3 5 4 AV BOARD (COMPONENT SIDE) 1-863-801- 12 (12) A K K 1 3 2 3 1 2 A A K A K K A K K A K K A K K HDMI OUT A MB BOARD CN205 B MB BOARD CN501 (Page 44) (Page 44) D101 J-10 D102 I-10 D103 C-8 D104 C-9 D105 C-9 D106 C-9 D301 G-3 D351 I-3 D371 D-1 IC102 I-8 IC302 G-3 IC371 F-2 IC400 G-11 IC401 F-10 IC402 F-11 IC500 H-9 IC501 H-10 IC600 D-11 IC601 H-12 IC602 B-12 IC603 C-12 IC604 I-12 IC605 C-12 Q301 H-7 Q302 H-7 Q303 G-7 Q304 H-6 Q305 H-6 Q306 G-6 Q307 H-6 Q308 H-6 Q309 G-6 Q310 D-2 Q351 I-4 Q352 I-3 Q353 I-3 Q372 D-2 Q374 D-1 • Semiconductor Location Ref. No. Location w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DVP-CX995V 59 59 DVP-CX995V 7-21. PRINTED WIRING BOARD – AV Board (Conductor Side) – • See page 42 for Circuit Boards Location. : Uses unleaded solder. G202 RV500 RV501 J102 J101 CN303 CN302 J103 C372 C271 C201 C375 C376 C378 C381 G201 C385 C358 J201 C355 C354 C353 C352 C351 C344 C342 C341 C324 C323 C322 C321 C314 C313 C310 C309 C306 C305 C302 C301 C277 C275 C274 C273 C272 C267 C265 C264 C263 C262 C261 IC301 C257 C255 C254 C253 C252 C251 C247 C245 C244 C243 C242 C241 C237 C235 C234 C233 C232 C231 C227 C225 C224 C223 C222 C221 C217 C215 C214 C213 C212 C211 C207 C205 C204 C203 CN304 CN301 C202 R410 C447 R422 R412 R419 R418 R417 R1016 R416 R415 R414 R413 R511 R512 C501 Q207 R119 C438 C469 C468 C467 C437 C436 C435 C434 C433 R451 C428 C427 C465 C425 C422 C518 C430 C415 C463 C421 C418 C424 C420 C417 C416 C413 C431 C412 C472 C471 C470 C411 C405 C432 C407 R405 C406 R629 C615 C612 R615 C606 C105 R619 FB602 C620 C618 R632 R614 C614 C619 R502 R611 C603 C607 C512 C605 C602 C601 C508 R522 C507 FB400 R521 C101 C419 C423 R455 R459 R477 C439 R129 C453 C458 C452 C457 C455 C451 C449 C454 C443 R409 C444 C464 C466 C448 C410 C462 C461 C459 C460 C608 C613 C408 R408 R407 R406 R411 Q208 C500 R519 R509 R537 C517 R612 FB601 C629 C632 R613 D606 C617 C600 R617 D608 Q103 C317 R618 Q205 C382 Q206 D607 D602 D601 D603 D604 D605 R440 Q203 Q204 R261 R262 R263 R264 R272 IC101 R271 R241 R118 R117 R116 R115 R114 IC201 R242 R243 Q104 R132 IC502 R110 C107 C506 C380 Q373 R101 R103 R345 R343 R342 R341 R344 R283 R281 R284 R282 Q202 R290 R289 R288 R287 R286 R359 R279 Q371 R373 C386 R229 R260 R374 R280 IC204 IC203 IC202 R230 R218 Q201 R214 R213 R212 R239 R208 R207 R211 R204 R203 R202 R201 C374 C377 C371 R240 C379 R302 R301 R307 R308 R380 R305 C373 R346 R306 R259 R250 R303 R249 R278 R270 R220 R219 R210 R277 R269 R238 R237 R228 R209 R227 R258 R257 R248 R247 R276 R275 R268 R217 R267 R232 R231 R234 R304 R285 R233 R224 R223 R222 R221 R252 R251 R254 R253 R244 C318 C604 C502 E E E E E E E E E E E E AV BOARD (CONDUCTOR SIDE) 1-863-801- 12 (12) (CHASSIS) (CHASSIS) AUDIO VIDEO R L 1 2 L R PB/CB PR/CR Y WOOFER CENTER REAR 5. 1CH OUTPUT FRONT COAXIAL 0PTICAL LINE OUT 8 7 6 5 4 3 2 1 S VIDEO OUT COMPONENT VIDEO OUT PCM/DTS/ DOLBY DIGITAL DIGITAL OUT 1 3 3 1 2 3 1 2 MB BOARD CN203 G DRIVER BOARD CN906 H PANEL-L BOARD CN1001 J 1 1 1 1 3 5 9 14 (AC IN) SWITCHING REGULATOR JL373 JL372 JL378 JL376 JL381 JL382 JL383 A B C D E F G H I J 1 2 3 4 5 6 7 8 9 10 11 12 13 (Page 44) (Page 62) (Page 64) D601 C-3 D602 C-3 D603 C-3 D604 C-3 D605 C-3 D606 C-3 D607 C-2 D608 C-2 IC101 I-3 IC201 E-7 IC202 E-10 IC203 E-9 IC204 E-8 IC301 B-11 IC502 G-3 Q103 I-5 Q104 I-5 Q201 C-7 Q202 C-7 Q203 C-10 Q204 C-11 Q205 C-9 Q206 C-10 Q207 C-8 Q208 C-8 Q371 D-11 Q373 D-12 • Semiconductor Location Ref. No. Location w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DVP-CX995V 60 60 DVP-CX995V CNP621 S622 (LOCK) JW823 CN621 CNP603 S621 M603 (DOOR) CNP602 CN611 JW822 CNP611 S611 (DOOR OPEN/CLOSE) S612 (POP-UP) M601 (TABLE) M602 (LOADING) CNP601 CNP82 Q81 (DISC DETECT) CNP83 D81 JW4 JW3 JW1 JW2 JW5 JW6 IC81 IC84 IC83 IC82 CN81 CN82 CN83 C81 R84 R85 R82 R81 R83 1-863-806- 12 (12) LOCK SW BOARD 1-863-804- 12 (12) LOADING SW BOARD (LOADING DETECT) 1 2 1 2 1 4 K DRIVER BOARD CN903 IN t OUT 1-863-809- 12 (12) DOOR MOTOR BOARD 1 7 1 5 L DRIVER BOARD CN904 M DOOR SW BOARD 1-863-808- 12 (12) 5 1 DOWN t UP CLOSE T OPEN 1-863-805- 12 (12) LOADING MOTOR BOARD 1 4 M M 1-863-810- 12 (12) D. SENS IN BOARD 1 2 1-863-811- 12 (12) D. SENS OUT BOARD 1 2 DISC DETECT 1-863-814- 12 (12) SENSOR BOARD 1 2 4 3 5 1 2 4 3 5 1 2 4 3 5 1 2 1 2 4 3 5 MB BOARD CN304 D A B C D E F G H 1 2 3 4 5 6 7 8 9 10 11 12 N DRIVER BOARD CN905 (Page 62) (Page 62) (Page 44) (Page 62) D81 G-11 IC81 H-6 IC82 H-7 IC83 F-7 IC84 H-8 Q81 D-10 • Semiconductor Location Ref. No. Location 7-22. PRINTED WIRING BOARDS – TABLE Section – • See page 42 for Circuit Boards Location. : Uses unleaded solder. w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DVP-CX995V 61 61 DVP-CX995V CNP603 CNP621 CN621 CN611 CNP602 CNP601 R83 R84 IC84 IC83 R81 R82 R85 C81 CN81 IC82 IC81 CN82 CN83 CNP611 S621 S622 M602 M601 M603 Q81 CNP82 CNP83 D81 S611 S612 4P 2P 2P 5P 7P 4P 820 820 RPI-1391 RPI-1391 820 820 680 0.1 7P RPI-1391 RPI-1391 2P 2P 5P (LOCK) PT483F1 2P 2P GL528V T.MOTOR T.MOTOR L.MOTOR L.MOTOR GND T_LOCK GND T_LOCK DOOR MOTOR DOOR MOTOR GND POPUP POPDOWN GND POPUP POPDOWN GND POPUP POPDOWN T_LOCK GND S+5V D.SENS GND D.SENS(OUT) LD_IN LD_OUT DR_OP DR_CLS DR_OP DR_CLS DR_OP DR_CLS GND LOADING DETECT (POP-UP) OPEN/CLOSE DOOR (LOADING) (TABLE) (DOOR) DISC DETECT (DISC DETECT) IC81-84 TABLE ADDRESS SENSOR TSENS4 DSENS TSENS3 TSENS2 TSENS1 S+5V 1 2 3 4 5 5 4 3 2 1 5 4 3 2 1 5 4 3 2 1 UP DOWN OPEN CLOSE 7-23. SCHEMATIC DIAGRAM – TABLE Section – (Page 63) (Page 63) (Page 63) (Page 52) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DVP-CX995V 62 62 DVP-CX995V 7-24. PRINTED WIRING BOARD – DRIVER Board – • See page 42 for Circuit Boards Location. : Uses unleaded solder. JW901 JW902 JW903 JW904 JW905 JW906 JW907 JW909 JW910 JW911 JW912 JW913 JW914 JW915 JW916 JW917 JW908 CN901 CN904 CN903 IC941 IC961 CN905 C907 G901 C914 C915 CN906 R941 Q942 R926 R932 C905 R943 R944 D935 Q952 Q951 Q931 Q941 R931 R936 C902 R908 C904 C903 R906 R909 R920 C906 R911 R923 R918 R924 R914 R928 R922 R917 R925 C908 R921 R937 R903 R905 R907 C910 R930 R919 R902 R929 R915 R935 R910 R916 R913 C913 C911 R901 R904 R912 R927 C909 R933 R934 C901 R945 R942 A B C D E F 1 2 3 4 5 6 7 1-863-813- 12 (12) DRIVER BOARD E E E E E (CHASSIS) DOOR MOTOR BOARD CNP602 L 1 7 LOADING MOTOR BOARD CNP601 N 1 4 1 4 1 10 1 10 1 10 LOADING SW BOARD CNP603 K C MB BOARD CN305 1 3 H AV BOARD CN303 (Page 60) (Page 60) (Page 60) (Page 44) (Page 59) D935 C-5 IC941 E-4 IC961 C-4 Q931 C-5 Q941 D-5 Q942 D-5 Q951 C-5 Q952 C-5 • Semiconductor Location Ref. No. Location w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DVP-CX995V 63 63 DVP-CX995V R901 R904 R911 R912 R913 R914 R902 R903 R905 R907 R942 R943 R944 R941 C901 R908 R945 R910 R915 C902 C903 R909 C905 R916 C904 R918 R919 C906 R917 C909 R925 R921 R926 R927 C908 C910 R930 R931 C911 R924 R922 R923 R932 Q952 R934 Q951 Q942 Q941 D935 R936 R937 C915 C914 R933 R935 C913 C907 R920 R928 R929 CN903 CN904 CN905 CN901 CN906 G901 R906 IC961 IC941 Q931 10 10 150k 150k 180k 180k 1 1 1 1 2.2k 2.2k 10k 1k 0.1 15k 22k 16k 16k 0.1 0.1 180k 0.1 220k 0.1 4.7k 1 0.1 100k 0.47 1k 150k 100k 150k 0.47 0.47 1 100k 0.1 100 100k 1k 2.2k UN2213-TX 2.2k UN2113-TX UN2213-TX UN2113-TX 02CZ15 -TE85L 2.2k 2.2k 47 25V 47 25V 100 100 0.1 2.2 50V 1 4.7k 1 4P 7P 4P 10P 3P (CHASSIS) 15k LA6510 LA6510 2SC2712-YG-TE85L DRI LDI LDO DRO LDI LDO DRI DRO REF1 OUT1 IN1- IN1+ VEE IN2+ IN2- OUT2 REF2 VCC VEE VCC VSENS2 VSENS1 LDO DRO LDI LDOUT DOOR OUT DRI GND GND DOOR MOTOR DOOR MOTOR TABLE MOTOR TABLE MOTOR LOADING MOTOR LOADING MOTOR T_LOCK POPUP POPDOWN GND(M) LD_IN LD_OUT DR_OP DR_CLS DOOR_SW LOAD_SW GND SW-12V(M) SW+12V(M) GND DOOR/LOADING MOTOR DRIVE TABLE MOTOR DRIVE Q951,952 LEVEL SHIFT LEVEL SHIFT Q941,942 REGULATOR LDM+ LDM- TBLM- DRM+ DRM- TBLM+ 7-25. SCHEMATIC DIAGRAM – DRIVER Board – • See page 69 for IC Block Diagrams. (Page 61) (Page 61) (Page 61) (Page 52) (Page 57) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DVP-CX995V 64 64 DVP-CX995V 7-26. PRINTED WIRING BOARD – PANEL-L Board – • See page 42 for Circuit Boards Location. : Uses unleaded solder. CNP1004 JW1001 JW1002 JW1003 JW1004 JW1005 JW1006 JW1007 JW1008 JW1009 JW1010 JW1011 JW1013 JW1014 JW1015 JW1016 JW1017 JW1018 JW1019 JW1020 JW1021 JW1022 JW1023 JW1024 JW1025 JW1028 JW1030 JW1031 JW1032 JW1033 JW1034 JW1035 JW1036 JW1037 JW1038 JW1039 C1038 T1081 INVERTER TRANSFORMER S1009 S1008 S1007 S1006 S1004 S1003 S1002 S1001 IC1002 D1004 C1039 D1003 D1002 CN1002 D1001 C1086 C1085 C1082 C1081 CN1003 JW1012 JW1026 JW1027 CN1001 L1081 L1082 C1042 C1037 C1043 C1044 R1001 R1022 R1012 R1021 D1084 R1004 Q1010 C1088 Q1009 Q1008 R1084 R1081 Q1007 R1082 R1051 R1063 R1062 D1081 Q1001 R1066 R1052 R1053 R1057 R1054 R1056 R1055 C1034 R1024 R1040 C1040 D1085 R1058 R1032 C1083 R1042 R1041 R1031 Q1002 R1059 R1007 R1033 R1036 R1006 C1031 R1008 R1014 Q1082 Q1081 D1083 Q1004 FB1001 R1005 Q1006 C1035 R1064 R1083 D1082 R1025 C1087 R1003 Q1083 D1086 R1002 C1089 R1035 R1023 C1032 C1036 R1065 R1013 Q1003 R1044 R1061 C1051 C1052 C1053 R1011 IC1001 E E E E FL1001 FLUORESCENT INDICATOR TUBE E E E E E PANEL-L BOARD 1-863-802- 12 (12) AV BOARD CN304 J 1 5 MB BOARD CN303 F 1 2 25 PANEL-R BOARD CN1101 P 1 9 24 E E 4 1 11 6 E S1001 – 1004, S1006 – 1009 Q KEY BOARD BOARD CNP503 SA-CD HDMI MULTI CANNEL D1004, S1001 FL OFF ONE/ ALL DISCS 1 3 1 4 FOLDER PICTURE MODE TIME/TEXT REPEAT LOAD 1 A B C D E F G H 1 2 3 4 5 6 7 8 9 (Page 66) (Page 44) (Page 59) (Page 66) D1001 B-5 D1002 B-4 D1003 B-2 D1004 G-6 D1081 B-6 D1082 B-6 D1083 B-6 D1084 B-6 D1085 C-6 D1086 D-6 IC1001 E-4 IC1002 H-6 Q1001 C-5 Q1002 C-4 Q1003 C-2 Q1004 F-5 Q1006 C-2 Q1007 C-2 Q1008 G-6 Q1009 F-7 Q1010 E-5 Q1081 C-7 Q1082 C-7 Q1083 C-5 • Semiconductor Location Ref. No. Location w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DVP-CX995V 65 65 DVP-CX995V C1038 R1084 R1051 R1052 R1053 R1054 R1055 R1056 R1061 R1062 R1063 R1064 R1065 R1066 R1035 L1082 C1088 C1089 C1087 R1083 D1085 C1086 D1086 D1082 D1084 D1083 D1081 C1082 L1081 R1081 C1085 C1083 R1044 C1035 R1033 R1031 R1011 R1012 R1013 R1014 C1034 R1032 R1059 R1058 R1057 R1003 S1002 S1001 R1004 S1003 R1005 S1004 S1007 S1006 R1001 R1002 C1031 R1041 Q1082 R1082 Q1081 C1081 R1021 R1023 R1022 R1024 R1025 C1042 C1044 C1043 R1040 CN1001 CN1002 CNP1004 FL1001 C1040 C1039 R1036 R1042 CN1003 FB1001 Q1009 Q1008 D1002 D1003 D1004 D1001 Q1010 Q1083 T1081 R1006 R1007 R1008 IC1001 IC1002 Q1001 Q1002 Q1003 Q1004 Q1006 Q1007 S1009 S1008 C1037 C1032 C1051 C1053 C1052 C1036 47 6.3V 10 10 10 10 10 10 10k 10 10 10 10 10 10 47k 0.1 0.1 0.1 3.9k UDZS-TE-17-30B 22 50V UDZS-TE-17-6.2B MA113-(TX) MA113-(TX) MA113-(TX) MA113-(TX) 0.01 100V 6.8k 22 50V 0.1 10 0.1 100 3.3k 47 47 47 150 0.1 100 100 100 100 1k 2.2k 2.2k 3.3k 2.2k 0.1 0 2SD1622-S-TD 6.8k 2SD1622-S-TD 22 50V 0 4.7k 4.7k 22 22 0.1 0.1 0.1 0 5P 9P 4P 0.1 47 6.3V 100 0 25P 0 DTC114EKA-T146 DTC114EKA-T146 SEL5E20C-S-TP SEL5E20C-S-TP SEL5821A-TP15 SEL5E20C-S-TP 2SC2412K 2SB1122-ST-TD 4.7k 10k 22k MSM9201-04GS-K NJL74H400A DTC114EKA-T146 DTC114EKA-T146 DTC114EKA-T146 DTC114EKA-T146 DTC114EKA-T146 DTC114EKA-T146 3300p 0.1 100p 100p 100p 39p KBDIN KBCIN KBDOUT KBCOUT KEY1 KEY3 KEY4 JOG-A JOG-B LED0 LED1 LED2 LED3 KEY0 KEY2 P1 P2 P3 P4 P5 P6 P7 P8 P9 P10 P11 P12 P13 P14 P15 P16 P17 P18 15G 1G 2G 3G 4G 5G 6G 7G 8G 9G 10G 11G 12G 13G 14G 1G 2G 3G 4G 5G 6G 7G 8G 9G 10G 11G 12G 13G 14G 15G P1 P2 P3 P4 P5 P6 P7 P8 P9 P10 P11 P12 P13 P14 P15 P16 P17 P18 KBCIN LED5 LED6 FLD_CS JOG-A JOG-B KEY4 KEY1 LED3 LED4 FLD_DATA FLD_CLK FLD_RST LED0 KBDOUT LED1 KEY3 LED2 LED6 LED5 KBDIN KBCOUT KEY0 KEY2 FLD_RST FLD_CS FLD_DATA FLD_CLK GND SW+5V SW-GND SW+5V KEYBORAD_DATA KEYBOARD_CLK GND KEY3 KEY4 LED5(DISC-CHANGE) LED6(DIRECT-SEARCH) SW+5V GND KEY1 JOG-A JOG-B EVER+3.3V KEY1 KEY3 KBDIN KBCIN KBDOUT KBCOUT GND LED0(PROGRESSIVE) LED1(SACD) LED2(MULTI-CH) LED3(FL OFF) LED4(VIDEO OFF) LED5(DISC CHANGE) GND KEY4 SW-12V KEY2 KEY0 LED6(DIRECT-SEARCH) NC VDISP1 16G 15G NC NC NC NC NC NC NC NC NC NC NC NC NC NC NC NC NC NC VDISP2 NC VFL2 NC NC NC NC VDD DA CP CS RESET OOSC1 OSC0 GND VFL1 NC NC P1 P2 P3 P4 P5 P6 P7 P8 P9 P10 P11 P12 P13 P14 P15 P16 P17 P18 NC NC 14G 13G 12G 11G 10G 9G 8G 7G 6G 5G 4G 3G 2G 1G NC NC NC NC NC NC GRID DRIVE FLUORESCENT INDICATOR TUBE -30V REGULATOR INVERTER TRANSFORMER Q1081,1082 OSC JOG_A JOG_B FLDDATA FLDCLK FLDCS FLDRST IR FL DRIVER REMOTE CONTROL RECEIVER HDMI SA-CD MULTI CHANNEL FL OFF Q1001-1004,1006,1007 LED DRIVE FL OFF REPEAT FOLDER ONE/ ALL DISCS PICTURE MODE TIME/ TEXT LOAD Q1008,1009 KEYBOARD DISABLE SWITCH 7-27. SCHEMATIC DIAGRAM – PANEL-L Board – • See page 68 for Waveforms. • See page 69 for IC Block Diagrams. (Page 52) (Page 57) (Page 67) (Page 67) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DVP-CX995V 66 66 DVP-CX995V 7-28. PRINTED WIRING BOARDS – PANEL-R Section – • See page 42 for Circuit Boards Location. : Uses unleaded solder. JW1101 JW1102 EP1199 CN1101 S1108 S1107 S1103 S1102 S1101 S1110 S1111 S1112 S1104 S1105 S1106 S1109 D1101 D1102 RE1101 JG1101 JW1103 C1199 R1103 R1104 R1105 R1106 R1107 R1108 R1109 R1110 R1111 R1112 R1113 R1114 R1115 R1117 R1116 R1118 R1101 R1102 L823 L822 J821 CNP503 L821 C823 L824 C822 C821 D801 CNP504 R801 C801 PANEL-R BOARD 1-863-803- 12 (12) PANEL-L BOARD CN1002 P 1 9 S1101 – 1112 (CHASSIS) x X H A DISC DETECT OPEN/CLOSE MENU TOP MENU DISPLAY RETURN PUSH ENTER (JOG STICK) DISC/AMS PUSH ENTER + 100 D1102, S1112 DIRECT SEARCH D1101, S1111 DISC CHANGE 1-863-812- 12 (12) KEY BOARD BOARD PANEL-L BOARD CNP1004 Q KEYBOARD 1-863-807- 12 (12) LED BOARD MB BOARD CN304 E 1 2 TABLE ILLUMINATION A B C D E F G H 1 2 3 4 5 6 7 8 9 10 11 (Page 64) (Page 44) (Page 64) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DVP-CX995V 67 67 DVP-CX995V D1102 R1116 R1103 R1114 R1104 R1106 S1101 R1101 R1102 S1102 S1103 S1109 S1104 R1105 S1106 D1101 R1117 R1110 S1108 S1107 R1111 R1112 R1113 S1105 S1111 S1110 R1115 S1112 R1108 R1107 C1199 R1109 CN1101 D801 C801 R801 CNP504 C821 L821 L824 L823 L822 CNP503 C822 C823 J821 R1118 EP1199 JG1101 RE1101 SEL5521C-TP15 2.2k 150 10k 1k 4.7k 2.2k 4.7k 2.2k SEL5821A-TP15 150 1k 2.2k 2.2k 4.7k 22k 22k 10k 0.1 47k 9P SELU5E23C-PTP15 0.1 47 2P 0.1 4P (CHASSIS) 0.1 470 10V 3.3k GND KEY3 KEY4 LED5(DISC-CHANGE) LED6(DIRECT-SEARCH) SW+5V GND KEY1 JOG-A JOG-B LED S+5V SW+5V KEYBOARD_CLK KEYBOARD_DATA KEYBOARD OPEN/CLOSE TOP MENU DISPLAY MENU DISC CHANGE DIRECT SEARCH RETURN +100 DISC EJECT DIRECT CHANGE DISC (JOG STICK) PUSH ENTER SEARCH DISC/AMS PUSH ENTER ROTARY ENCODER 7-29. SCHEMATIC DIAGRAM – PANEL-R Section – (Page 65) (Page 52) (Page 65) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DVP-CX995V 68 68 DVP-CX995V 1 IC104 4 (RFOUT) DVD/SA-CD/CD play mode DVD/SA-CD play: 200 mV/DIV, 100 ns/DIV CD play: 200 mV/DIV, 200 ns/DIV DVD play: 510 mVp-p SA-CD play: 550 mVp-p CD play: 490 mVp-p 2 IC401 ol (RFSACD) SA-CD play mode 200 mV/DIV, 100 ns/DIV 660 mVp-p 3 IC104 ya (OUT-CLK) 2 V/DIV, 10 ns/DIV 25 ns 4.7 Vp-p 7 IC205 7 (I2S_BCLK_OUT) 2 V/DIV, 10 ns/DIV 25 ns 5 Vp-p 74 µs 3.9 Vp-p 4 IC401 yd (OUT-DVALID) 2 V/DIV, 50 µs/DIV 20.8 µs 4.3 Vp-p q; IC205 th (DAC-LRCLK) 2 V/DIV, 10 µs/DIV 5 IC201 1 1 V/DIV, 20 ns/DIV 37 ns 2 Vp-p qa IC304 qg (5.0M) 1 V/DIV, 100 ns/DIV 200 ns 2.5 Vp-p 6 IC205 1 (YC_CLKOUT) 2 V/DIV, 20 ns/DIV 37 ns 4 Vp-p 8 IC205 ta (DAC-SCLK) 2 V/DIV, 200 ns/DIV 324 ns 4.4 Vp-p 40.8 ns 4.2 Vp-p 9 IC205 tg (DAC-PCMCLK) 2 V/DIV, 20 ns/DIV wa IC500 es (CLKIN) 1 V/DIV, 20 ns/DIV 37 ns 3.5 Vp-p ws IC500 ej (CR/B) (Color bar) 0.5 V/DIV, 20 µs/DIV H 0.7 Vp-p wd IC500 ek (CB/R) (Color bar) 0.5 V/DIV, 20 µs/DIV H 0.7 Vp-p wf IC500 el (Y/G) (Color bar) 0.5 V/DIV, 20 µs/DIV 1 Vp-p wh IC500 rd (Y) (Color bar) 0.5 V/DIV, 20 µs/DIV 1 Vp-p wg IC500 rs (C) (Color bar) 0.5 V/DIV, 20 µs/DIV 0.8 Vp-p wj IC500 rf (V) (Color bar) 1 V/DIV, 20 µs/DIV 1.4 Vp-p es IC102 3 (VIDEO_IN) (Color bar) 1 V/DIV, 20 µs/DIV 1.4 Vp-p rd IC102 ed (VIDEO_OUT) (Color bar) 1 V/DIV, 20 µs/DIV 2.6 Vp-p wk IC500 yd (CLKIN_2) 1 V/DIV, 20 ns/DIV 37 ns 3.5 Vp-p wl IC600 6 (MCLK) 1 V/DIV, 20 ns/DIV 40.7 ns 3.2 Vp-p 20.8 µs 3.2 Vp-p e; IC600 qa (WS) 1 V/DIV, 5 µs/DIV 325 ns 3.2 Vp-p ea IC600 qs (SCK) 1 V/DIV, 0.1 µs/DIV ed IC102 6 (C_IN) (Color bar) 0.5 V/DIV, 20 µs/DIV 0.8 Vp-p rs IC102 ea (C_OUT) (Color bar) 1 V/DIV, 20 µs/DIV 1.8 Vp-p ef IC102 8 (Y_IN) (Color bar) 0.5 V/DIV, 20 µs/DIV 1 Vp-p eg IC102 qs (Y_IN) (Color bar) 1 V/DIV, 20 µs/DIV 1 Vp-p r; IC102 wf (Y_OUT) (Color bar) 1 V/DIV, 20 µs/DIV 2 Vp-p ra IC102 wl (Y_OUT) (Color bar) 1 V/DIV, 20 µs/DIV 2 Vp-p eh IC102 qg (CB_IN) (Color bar) 0.5 V/DIV, 20 µs/DIV H 640 mVp-p el IC102 ws (CB_OUT) (Color bar) 1 V/DIV, 20 µs/DIV H 1.5 Vp-p ej IC102 qj (CR_IN) (Color bar) 0.5 V/DIV, 20 µs/DIV H 650 mVp-p ek IC102 w; (CR_OUT) (Color bar) 1 V/DIV, 20 µs/DIV H 1.5 Vp-p ta IC1001 yg (OSC0) 500 mV/DIV, 200 ns/DIV 460 ns 1.6 Vp-p • Waveforms – MB Board – – AV Board – – PANEL-L Board – w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 69 DVP-CX995V IC102 FAN8035L • IC Block Diagrams – MB Board – DO6+ 25 PGND2 26 IN1– 1 OUT1 2 IN2+ 3 IN2– 4 OUT2 5 IN3+ 6 IN4+ 9 IN4– 10 IN3– 7 OUT3 8 OUT4 11 IN5+ 12 14 OUT5 13 IN5– 15 CTL 16 FWD 17 REV 20 MUTE34 18 SGND 19 MUTE12 22 TSD-M 21 MUTE5 24 DO6– 23 PVCC2 DRIVER POWER SAVE VREF OPOUT2 40 PS 39 PVCC1 38 DO1+ 37 SVCC 44 VREF 43 OPIN2+ 42 OPIN2– 41 DO5– 27 DO5+ 28 DO4– 29 DO4+ 30 DO3– 31 PGND1 33 DO3+ 32 DO2+ 35 DO1– 36 DO2– 34 OPOUT1 45 OPIN1– 46 OPIN1+ 47 IN1+ 48 DRIVER DRIVER DRIVER DRIVER DRIVER MUTING12 CONTROL THERMAL SHUT DOWN MUTING34 MUTING5 IC206 SN74LV08APWR 1 2 3 4 5 6 7 8 9 10 11 12 13 14 1A 1B 1Y 2A 2B 2Y GND VCC 4B 4A 4Y 3B 3A 3Y www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 70 DVP-CX995V IC403 HY57V641620ETP-HDR I/O BUFFER & LOGIC SENSE AMP & I/O GATE STATE MACHINE Y DECODERS X DECODERS MEMORY CELL ARRAY ROW PRE DECODERS REFRESH VSS 54 DQ15 53 VSSQ 52 DQ14 51 DQ13 50 VDDQ 49 DQ12 48 DQ11 47 VSSQ 46 DQ10 45 DQ9 44 VDDQ 43 DQ8 42 VSS 41 NC 40 CLK 38 UDQM 39 CKE 37 NC 36 VDD 1 DQ0 2 VDDQ 3 DQ1 4 DQ2 5 VSSQ 6 DQ3 7 DQ4 8 VDDQ 9 DQ5 10 DQ6 11 VSSQ 12 DQ7 13 LDQM 15 VDD 14 /WE 16 /CAS 17 /RAS 18 /CS 19 BA0 20 BA1 21 A10/AP 22 A0 23 A1 24 VDD 27 ADDRESS BUFFER COLUMN PRE DECODERS INTERNAL ROW COUNTER COLUMN ADD COUNTER BURST COUNTER MODE REGISTER DATA OUT CONTROL ADDRESS REGISTERS SELF REFRESH LOGIC & TIMER A2 25 A3 26 A11 35 A9 34 A8 33 A7 32 A6 31 A5 30 A4 29 VSS 28 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 71 DVP-CX995V IC501 AK4358VQ-L SCF DAC DATT SCF DAC DATT 37 LOUT4– 38 LOUT4+ SCF DAC DATT 39 ROUT3– 40 ROUT3+ SCF DAC DATT 41 LOUT3– 42 LOUT3+ SCF DAC DATT 43 ROUT2– 44 ROUT2+ SCF DAC DATT 45 LOUT2– 46 LOUT2+ SCF DAC DATT SCF DAC DATT 47 ROUT1– 48 ROUT1+ DSD PCM AUDIO I/F 8 PDN 5 DZF1 6 CAD0 3 DZF3 4 DZF2 1 LOUT1– 2 LOUT1+ 9 BICK 10 MCLK 11 DVDD 12 DVSS 13 SDTI4 14 SDTI1 15 SDTI2 16 SDTI3 17 LRCK CONTROL REGISTER 18 I2C 25 DSDL1 26 DSDR1 33 ROUT4+ 32 ROUT4– 27 DSDL2 28 DSDR2 29 DSDL3 30 DSDR3 19 CCLK/SCL 21 CSN/CAD1 20 CDTI/SDA 24 DSDR4 22 DCLK 23 DSDL4 31 DIF0 7 ACKSN 36 AVSS 35 AVDD 34 VREFH 1 N. C. 2 N. C. 3 VIN1 4 DCCNT1 5 GND 6 VIN2 7 MUTE1 8 VIN3 9 N. C. 10 N. C. 11 N. C. 12 VIN4 13 DCCNT2 14 GND 15 VIN5 16 MUTE2 17 VIN6 18 –VCC4 36 N. C. 35 N. C. 34 +VCC1 33 VOUT1 32 GND 19 –VCC3 6dB +VCC DR 6dB DR 6dB DR 31 VOUT2 30 N. C. 29 VOUT3 28 –VCC1 27 –VCC2 26 N. C. 25 +VCC2 24 VOUT4 23 GND 22 VOUT5 21 N. C. 20 VOUT6 6dB +VCC DR 6dB DR 6dB DR IC102 LA73053-TLM-E – AV Board – IC400, 601 TK11118CSCL-G 1 2 3 5 4 VCONT GND NP VIN VOUT CONTROL CIRCUIT OVER HEAT & OVER CURRENT PROTECTION BANDGAP REFERENCE www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 72 DVP-CX995V IC402 HY57V161610ETP-7DR A9 A8 A7 A6 A5 A4 VSS A11-BA A10/AP A0 A1 A2 A3 VDD VDD DQ0 DQ1 VSSQ DQ2 DQ3 VCCQ DQ4 DQ5 VSSQ DQ6 DQ7 VDDQ VSS DQ15 DQ14 VSSQ DQ13 DQ12 VCCQ DQ11 DQ10 VSSQ DQ9 DQ8 VDDQ CAS RAS 31 32 29 30 26 27 28 21 20 19 23 22 25 24 2 1 4 3 6 5 8 7 10 9 11 13 12 49 50 46 48 44 47 45 42 43 39 40 36 READ DATA REGISTER INPUT DATA REGISTER OUTPUT BUFFERS INPUT BUFFERS SENSE AMPLIFIER COLUMN DECODERS MEMORY CELLS WORD DRIVERS ROW DECODERS COLUMN ADDRESS BUFFERS UDQM 35 CLK 34 CKE 33 NC 37 NC 38 41 I/O CONTROLLER PROGRAMING REGISTER 16 WE 15 17 CS 18 LDQM 14 ROW ADDRESS BUFFERS INTERNAL COLUMN ADDRESS COUNTOR LATENCY & BURST CONTROLLER INTERNAL ROW ADDRESS COUNTOR TIMING REGISTER BANK CONTROLLER www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 73 DVP-CX995V IC500 ADV7300AKST 1 VDD 2 P_Y0 3 P_Y1 4 P_Y2 5 P_Y3 6 P_Y4 7 P_Y5 8 P_Y6 9 P_Y7 10 VDD 11 GND 12 P_Y8 13 P_Y9 14 P_C0 15 P_C1 16 P_C2 P_C3 P_C4 SPI ALS8 SDA SCLK P_HSYNC P_VSYNC P_BALNK P_C5 P_C6 P_C7 P_C8 P_C9 RTC CLKIN_A 48 S_BLANK 47 RSET1 46 VREF 45 COMP1 44 V 43 Y 42 C 41 VAA 40 GND 39 Y/G 38 CB/R 37 CR/B 36 COMP2 35 RSET2 34 EXT_LF 33 RESET 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 GND CLKIN_B S9 S8 S7 S6 S5 GND VDD S4 S3 S2 S1 S0 S_HSYNC S_VSYNC 64 63 62 61 60 59 58 57 56 55 54 53 52 51 50 49 TIMING GENERATOR DEINTERLEAVE Y CR CB TEST PATTERN SHARPNESS & ADAPTIVE FILTER CONTROL Y COLOR/CR COLOR/CB COLOR 4:2:2 TO 4:4:4 DEINTERLEAVE CR CB PS 8X HDTV 2X TIMING GENERATOR Y V U TEST PATTERN DNR GAMMA COLOR CONTROL SYNC INSERTION LUMA & CHROMA FILTERS FSC MODULATION CGMS WSS 2XOVERSAMPLING DAC DAC DAC DAC DAC DAC CLOCK CONTROL & PLL UV SSAF RGB MATRIX SD 16X IC501 TK11125CSCL-G 1 2 3 5 4 VCONT GND NP VIN VOUT CONTROL CIRCUIT OVER HEAT & OVER CURRENT PROTECTION BANDGAP REFERENCE www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 74 DVP-CX995V IC600 SII9030CTU-1.1 41 48 49 29 1 30 61 24 CI2CA IOVCC 47 IOGND 46 CGND 45 CVCC18 D23 50 D22 51 D21 52 D20 53 D19 54 D18 55 D17 56 D16 57 D15 58 D14 59 CVCC18 60 CGND TX0– HSYNC 2 VSYNC 3 CGND 4 CVCC18 5 SPDIF 6 MCLK 7 SD3 8 SD2 9 SD1 10 SD0 11 WS 12 SCK 13 IOVCC 14 IOGND 15 CGND 16 CVCC18 17 INT 18 HPD 19 DSDA 20 DSCL TX0+ D13 62 D12 63 D11 64 D10 65 D9 66 IDCK 67 D8 68 D7 69 D6 70 D5 71 IOVCC 72 IOGND 73 CGND 74 CVCC18 75 D4 76 D3 77 D2 78 D1 79 D0 80 DE EXT_SWING 25 AGND 34 AVCC 37 AGND 38 PVCC2 39 PGND2 40 NC 31 AGND 28 AVCC 23 PVCC1 22 PGND1 21 RSVDL 42 RESET# 43 CSCL 44 CSDA 32 33 TX1– TX1+ 35 36 TX2– TX2+ 26 27 TXC– TXC+ I2C SLAVE E-DDC MASTER RECEIVER SENS + INTERRUPT LOGIC VIDEO DATA CAPTURE / DE GEN / 656 LOGIC BLOCK AUDIO DATA CAPTURE LOGIC BLOCK REGISTERS CONFIGURATION LOGIC BLOCK PANEL LINK TMDS DIGITAL CORE XOR CSC 4: 2: 2 TO 4: 4: 4 HDCP KEYS EEPROM HDCP ENCRYPTION ENGINE IC603 TK11150CSCL-G 5 1 2 3 REG 4 VOLTAGE CONTROL COMP VIN VOUT CONTROL GND NOISE BYPASS IC604 TK11133CSCL-G 1 6 2 3 5 REG 4 VOLTAGE CONTROL COMP VIN GND VOUT CONTROL GND NOISE BYPASS IC941, 961 LA6510 – DRIVER Board – VOUT1 +VIN1 VSENCE1 –VIN1 –VIN2 VCC +VIN2 VOUT2 VSENCE2 VEE 1 2 3 4 5 6 7 8 9 10 + – + – www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 75 DVP-CX995V IC1001 MSM9201-04GS-K – PANEL-L Board – 61 62 40 39 38 59 60 57 58 55 56 53 54 51 52 49 50 47 48 45 46 43 44 41 42 65 63 64 66 68 67 70 71 72 73 74 75 76 77 78 79 80 69 37 36 35 34 33 32 31 30 29 28 27 26 25 24 23 22 21 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 1 2 COMMAND DECODER CONTROL CIRCUIT GRID DRIVER PORT DRIVER TIMING GENERATOR1 TIMING GENERATOR2 8BIT SHIFT REGISTER WRITE ADDRESS COUNTER READ ADDRESS COUNTER OSCILLATOR DUTY CONTROL DIGIT CONTROL ADDRESS SELESTOR ADRAM 24W x 4B DCRAM 24W x 8B CGRAM 240W x 35B CGRAM 16W x 35B AD DRIVER SEGMENT DRIVER COM23 COM24 OSC0 VFL1 GND OSC1 CS RESET DA VDD P1 P2 P3 P4 VFL2 NC VDISP2 AD1 AD2 CP SEG1 SEG2 SEG3 SEG4 SEG5 SEG6 SEG7 SEG8 SEG9 SEG10 SEG11 SEG12 SEG13 SEG14 SEG15 SEG16 SEG17 SEG18 AD3 AD4 COM2 COM1 VDISP1 SEG35 SEG34 SEG33 SEG32 SEG31 SEG30 SEG29 SEG28 SEG27 SEG26 SEG25 SEG24 SEG23 SEG22 SEG21 SEG20 SEG19 COM21 COM22 COM19 COM20 COM17 COM18 COM15 COM16 COM13 COM14 COM11 COM12 COM9 COM10 COM7 COM8 COM5 COM6 COM3 COM4 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 76 DVP-CX995V • IC Pin Function Description MB BOARD IC104 STE6317ATXXY (DVD INTERFACE) Pin No. Pin Name I/O Description 1 IREF I Connected to the ground 2 GNDAI - Ground terminal (analog system) 3 RFIN I RF path data input terminal (after AC coupling) 4 RFOUT O RF path data output terminal (before AC coupling) 5 VCC18 - Power supply terminal (+1.8V) (analog system) 6 A I A signal input from the optical pick-up block 7 GNDMN - Ground terminal (analog system) 8 B I B signal input from the optical pick-up block 9 VCC33MN - Power supply terminal (+3.3V) (analog system) 10 REFD O Reference voltage output terminal (+2.1V) (for laser diode) 11 VCC18MN - Power supply terminal (+1.8V) (analog system) 12 D I D signal input from the optical pick-up block 13 VCC18IS - Power supply terminal (+1.8V) (analog system) 14 C I C signal input from the optical pick-up block 15 VCC33IS - Power supply terminal (+3.3V) (analog system) 16 GNDAIS - Ground terminal (analog system) 17 VCC33SD - Power supply terminal (+3.3V) (analog system) 18 VCC18SD - Power supply terminal (+1.8V) (analog system) 19 GNDSD - Ground terminal 20 F I F signal input from the optical pick-up block 21 E I E signal input from the optical pick-up block 22 VSHIELDIS - Ground terminal (analog system) 23 VCC18ADC - Power supply terminal (+1.8V) (analog system) 24 GNDADC - Ground terminal (analog system) 25 VSHIELDADC - Ground terminal (analog system) 26 VCC33ADC - Power supply terminal (+3.3V) (analog system) 27 GNDDAC - Ground terminal (analog system) 28 DISC O Sled motor drive signal output terminal 29 SLED O Sled motor drive signal output terminal 30 REFEXT I Connected to the ground 31 REFGND - Ground terminal 32 REF O Reference voltage output terminal (+2.7V) (for D/A converter) 33 FACT O Focus coil drive signal output terminal 34 TACT O Tracking coil drive signal output terminal 35 VCC18DAC - Power supply terminal (+1.8V) (analog system) 36 MUTE_SP O Muting on/off control signal output to the spindle motor driver "L": muting on 37 MUTE_DRV O Muting on/off control signal output to the focus/tracking coil driver and sled motor driver "L": muting on 38, 39 FIN, RIN O Loading motor drive signal output terminal "L": motor off Not used 40 INSW I Disc tray close detection signal input terminal "L": Disc tray is closed Fixed at "L" in this set 41 VSS - Ground terminal (digital system) 42 VDD33 - Power supply terminal (+3.3V) (digital system) 43 DVD/CD O DVD/CD selection signal output to the optical pick-up block "L": CD, "H": DVD 44 SP O Spindle motor drive PWM signal output terminal 45 INLIM I Limit in detection signal input from the optical pick-up block The optical pick-up is inner position when "H" www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 77 DVP-CX995V Pin No. Pin Name I/O Description 46 OUTSW I Disc tray open detection signal input terminal "H": Disc tray is closed Fixed at "H" in this set 47 DGND - Ground terminal (digital system) 48 VDD18 - Power supply terminal (+1.8V) (digital system) 49, 50 PD (6), PD (5) O Internal signal monitor output terminal Not used 51 DSPCLK O Internal signal monitor output terminal Not used 52 DSPDAT O Internal signal monitor output terminal Not used 53 DSPSTRB O Internal signal monitor output terminal Not used 54, 55 PD (1), PD (0) O Internal PDM signal monitor output terminal Not used 56 VSS - Ground terminal (digital system) 57 VDD33 - Power supply terminal (+3.3V) (digital system) 58 OUT-ERR O Error signal output to the CPU 59 OUT-EVALID O Word clock signal output to the CPU 60 VSS - Ground terminal (digital system) 61 OUT-CLK O Bit clock signal output to the CPU 62 VDD18 - Power supply terminal (+1.8V) (digital system) 63 OUT-DVALID O PCLK signal output to the CPU 64 OUT-DATA O Serial audio/video data output to the CPU 65 OUT-SYNC O Error signal and V4 signal output to the CPU 66 SCL I I2C bus clock signal input from the CPU 67 SDA I/O I2C two-way data bus with the CPU, interlace/progressive converter, video D/A converter and HDMI transmitter 68, 69 PE (3), PE (2) - Not used 70 SPDIR I Spindle motor rotation direction detection signal input from spindle motor driver "L": reverse direction, "H": forward direction 71 IRQ_FE O Interrupt request signal output to the CPU 72 VSS - Ground terminal (digital system) 73 VDD33 - Power supply terminal (+3.3V) (digital system) 74 PF (1) O Internal signal monitor output terminal Not used 75 DSPSTRB2 O Internal signal monitor output terminal Not used 76 VSS - Ground terminal (digital system) 77 VDD18 - Power supply terminal (+1.8V) (digital system) 78 PG (1) I Boot mode selection mode signal input terminal "L": standalone mode, "H": EMU mode Fixed at "L" in this set 79 PG (0) I Boot mode selection mode signal input terminal "H": standalone/EMU mode Fixed at "H" in this set 80 TEST I Input terminal for the test 81 RESET_N I Reset signal input from the CPU "L": reset 82 VSSADC - Ground terminal (analog system) 83 VDD18ADC - Power supply terminal (+1.8V) (analog system) 84 GNDPLL - Ground terminal (analog system) 85 CKOUT - Not used 86 FREOUT - Not used 87 FREIN O 27 MHz clock signal input terminal 88 VCC18PLL - Power supply terminal (+1.8V) (analog system) 89 LD1 O Laser diode control signal (for DVD) output terminal 90 LD2 O Laser diode control signal (for CD) output terminal 91 VCCA33 - Power supply terminal (+3.3V) (analog system) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 78 DVP-CX995V Pin No. Pin Name I/O Description 92 TWINSEL I Connected to the ground 93, 94 LMD1, LMD2 I Laser diode monitor input from the optical pick-up block 95 GNDL - Ground terminal (analog system) 96 TST-PM O Output terminal for the analog test 97 TST-SLICE O Output terminal for the analog test 98 TST-ADC I Not used 99 RFSACD O RF (for SACD) signal output to the SACD media player 100 VBGFILT I Connected to the ground through the capacitor www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 79 DVP-CX995V MB BOARD IC205 STE5588CVB (CPU) Pin No. Pin Name I/O Description 1 FUR_RST O Reset signal output to the SACD media player "L": reset 2 DAC-PCMOUT3 O PCM audio data output to the D/A converter and HDMI transmitter 3 YC_CLKOUT O 27 MHz clock signal output to the interlace/progressive converter 4 VDD3-3 - Power supply terminal (+3.3V) 5 VSS - Ground terminal 6 I2S_DATA_OUT O I2S bus data output to the SACD media player 7 I2S_BCLK_OUT O I2S bus clock signal output to the SACD media player 8 I2S_BFLAG_OUT O I2S bus flag output to the SACD media player 9 VIDEO_RST O Reset signal output to the interlace/progressive converter, video D/A converter and HDMI transmitter "L": reset 10 RTS I UART flow control signal input terminal 11 BE_BUSY O Busy signal output to the system controller 12 CTS O UART flow control signal output terminal 13 CS I Chip select signal input from the system controller 14 VDD1-8 - Power supply terminal (+1.8V) 15 VSS - Ground terminal 16 B-DATA I Serial audio/video data input from the DVD interface 17 B-BCLK I Bit clock signal input from the DVD interface 18 B-FLAG I PCLK signal input from the DVD interface 19 B-SYNC I Error signal input from the DVD interface 20 WCLK I Word clock signal input from the DVD interface 21 B-V4 I V4 signal input from the DVD interface 22 ADAC_CS O Chip select signal output to the D/A converter 23 VDD-RGB - Power supply terminal Not used 24 VSS-RGB - Ground terminal 25 B-OUT O RGB (blue) signal output terminal Not used 26 G-OUT O RGB (green) signal output terminal Not used 27 R-OUT O RGB (red) signal output terminal Not used 28 V-REF-RG - Reference voltage terminal 29 I-REF-RG - Reference current terminal 30 VDD-YCC - Power supply terminal Not used 31 VSS-YCC - Ground terminal 32 Y-OUT O Y signal output terminal Not used 33 C-OUT O Chroma signal output terminal Not used 34 VC-OUT O Component video signal output terminal Not used 35 V-REF-YC - Reference voltage terminal 36 I-REF-YC - Reference current terminal 37 VDD1-8 - Power supply terminal (+1.8V) 38 VSS - Ground terminal 39 to 46 YC0 to YC 7 O Digital video signal output to the interlace/progressive converter 47 VDD3-3 - Power supply terminal (+3.3V) 48 VDD-PCM - Power supply terminal (+1.8V) 49 VSS-PCM - Ground terminal 50 VSS - Ground terminal 51 DAC-SCLK O Bit clock signal output to the D/A converter www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 80 DVP-CX995V Pin No. Pin Name I/O Description 52 to 54 DAC-PCMOUT0 to DAC-PCMOUT2 O PCM audio data output to the D/A converter 55 DAC-PCMCLK O Master clock signal output to the SACD media player, D/A converter and HDMI transmitter 56 DAC-LRCLK O L/R sampling clock signal output to the D/A converter 57 SPDIF-OUT O SPDIF signal output to the digital out jack and HDMI transmitter 58 to 63 SMI-ADR (4) to SMI-ADR (9) O Address signal output to the SD-RAM 64 VDD1-8 - Power supply terminal (+1.8V) 65 VSS - Ground terminal 66 to 69 SMI-ADR (3) to SMI-ADR (0) O Address signal output to the SD-RAM 70 to 73 SMI-ADR (10) to SMI-ADR (13) O Address signal output to the SD-RAM 74 SMI-CS (0) O Chip select signal output to the SD-RAM 75 SMI-CS (1) O Chip select signal output terminal Not used 76 SMI-RAS O Row address signal output to the SD-RAM 77 SMI-CAS O Column address signal output to the SD-RAM 78 SMI-WE O Write enable signal output to the SD-RAM 79 SMI-DQML O Write mask signal output to the SD-RAM (lower byte) 80 SMI-DQMU O Write mask signal output to the SD-RAM (upper byte) 81 VDD3-3 - Power supply terminal (+3.3V) 82 SMI-CLKIN I 133 MHz clock signal input terminal 83 VSS - Ground terminal 84 to 93 SMI-DATA (0) to SMI-DATA (9) I/O Two-way data bus with the SD-RAM 94 VDD1-8 - Power supply terminal (+1.8V) 95 SMI-CLKOUT O 133 MHz clock signal output to the SD-RAM 96 VSS - Ground terminal 97 to 102 SMI-DATA (10) to SMI-DATA (15) I/O Two-way data bus with the SD-RAM 103 TMODE_SW I Test mode on/off control signal input from the system controller "H": test mode on 104 +5V_CONT_B O Power on/off control signal output terminal for HDMI section (+5V) Not used 105 ADY_CS O Chip select signal output terminal Not used 106 ADC-PCMCLK O PCM clock signal output terminal Not used 107 VDD3-3 - Power supply terminal (+3.3V) 108 VSS - Ground terminal 109 TRST I Reset signal input terminal (for JTAG) 110 TMS I Mode selection signal input terminal (for JTAG) 111 TDO O Data output terminal (for JTAG) 112 TDI I Data input terminal (for JTAG) 113 TCK I Clock signal input terminal (for JTAG) 114 ADY_BYPASS O Bypass signal output terminal Not used 115 BOOT_MODE O Boot mode selection signal output terminal Not used 116 WP O Write protect signal output terminal Not used 117 CPU-OE O Output enable signal output to the flash memories 118 CPU-PROCLK O Not used 119 VDD1-8 - Power supply terminal (+1.8V) 120 PIX-CLK I 27 MHz clock signal input terminal www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 81 DVP-CX995V Pin No. Pin Name I/O Description 121 VSS - Ground terminal 122 VDD-PLL - Power supply terminal (+1.8V) 123 VSS-PLL - Ground terminal 124 RESET I Reset signal input from the system controller "L": reset 125 IRQ (2) I Interrupt request signal input from the SACD media player 126 IRQ (1) I Interrupt request signal input from the HDMI transmitter 127 IRQ (0) I Interrupt request signal input from the DVD interface 128 CPU-BE (0) O Write enable signal output to the flash memories 129 CPU-BE (1) O Write enable signal output terminal Not used 130 CPU-RW O Read/write selection signal output to the SACD media player "L": read, "H": write 131 CPU-WAIT I Chip wait signal input from the SACD media player 132 CPU-CE (3) O Chip enable signal output to the flash memory 133 CPU-CE (2) O Chip select signal output to the SACD media player 134 CPU-CE (1) O Chip enable signal output to the flash memory 135 CPU-CE (0) O Chip enable signal output terminal Not used 136 VDD3-3 - Power supply terminal (+3.3V) 137 VSS - Ground terminal 138 CPU-RAS1 O Row address signal output terminal Not used 139, 140 CPU-CAS0, CPU-CAS1 O Column address signal output terminal Not used 141 to 148 CPU-DATA (0) to CPU-DATA (7) I/O Two-way data bus with the flash memories and SACD media player 149 VDD1-8 - Power supply terminal (+1.8V) 150 VSS - Ground terminal 151 to 158 CPU-DATA (8) to CPU-DATA (15) I/O Two-way data bus with the flash memories and SACD media player 159 VDD3-3 - Power supply terminal (+3.3V) 160 VSS - Ground terminal 161 to 167 CPU-ADR (1) to CPU-ADR (7) O Address signal output to the flash memories and SACD media player 168 to 170 CPU-ADR (8) to CPU-ADR (10) O Address signal output to the flash memories 171 VDD1-8 - Power supply terminal (+1.8V) 172 VSS - Ground terminal 173 to 183 CPU-ADR (11) to CPU-ADR (21) O Address signal output to the flash memories 184 VDD3-3 - Power supply terminal (+3.3V) 185 VSS - Ground terminal 186 FE_RST O Reset signal output to the DVD interface "L": reset 187 RSERROR I Error signal input from the DVD interface 188 A_MUTE O Audio muting on/off control signal output terminal "L": muting on 189 LETTER O Letter box control signal output terminal Not used 190 H_SCL_BP O I2C bus clock signal output terminal Not used 191 SQUEEZE O Squeeze control signal output terminal Not used 192 H_SDA_BP I/O I2C two-way data bus terminal Not used 193 I2S_SYNC_OUT O Sector sync signal or absolute time sync signal output to the SACD media player 194 BE_SDA I/O I2C two-way data bus with the DVD interface, interlace/progressive converter, video D/A converter and HDMI transmitter www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 82 DVP-CX995V Pin No. Pin Name I/O Description 195 BE_SCL O I2C bus clock signal output to the DVD interface, interlace/progressive converter, video D/A converter and HDMI transmitter 196 I2S_WCLK_OUT O I2S bus word clock signal output to the SACD media player 197 IF_TXD O UART transmit data output to the system controller 198 VDD1-8 - Power supply terminal (+1.8V) 199 VSS - Ground terminal 200 IF_RXD I UART receive data input from the system controller 201 FCNG_TXD O UART transmit data output for data writing to the flash memory 202 TRIGGER-IN I Trigger signal input terminal 203 TRIGGER-OUT O Trigger signal output terminal 204 ADAC_RESET O Reset signal output terminal Not used 205 FCNG_RXD I UART receive data input for data writing to the flash memory 206 SI I Serial data input terminal Not used 207 SO O Serial data output to the D/A converter 208 SCLK O Serial data transfer clock signal output to the D/A converter www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 83 DVP-CX995V MB BOARD IC304 uPD703260-YGF-S30-JBT-A (SYSTEM CONTROLLER) Pin No. Pin Name I/O Description 1, 2 KEY1, KEY0 I Front panel keys input terminal (A/D input) 3 AVDD - Power supply terminal (+3.3V) 4 AVSS - Ground terminal 5, 6 NC O Not used 7 AVREF I Reference voltage (+3.3V) input terminal 8 JOG_A I Jog dial pulse input from the rotary encoder (A phase input) 9 JOG_B I Jog dial pulse input from the rotary encoder (B phase input) 10 FLMD0 I Flash memory data write mode control signal input terminal 11 VDD - Power supply terminal (+3.3V) 12 REGC O Connection terminal to the regulator capacitor 13 VSS - Ground terminal 14 5.0M I System clock input terminal (5 MHz) 15 5.0M O System clock output terminal (5 MHz) 16 RESET I System reset signal input from the reset signal generator "L": reset For several hundreds msec. after the power supply rises, "L" is input, then it change to "H" 17 GND - Ground terminal 18 OPEN - Not used 19 HDMI_RST O Reset signal output terminal Not used 20 KEY_INT I Wake up signal input from front panel keys or remote commander 21 232C_INT I Wake up signal input terminal for RS-232C Not used 22 DEBUGRST O Reset signal output terminal Not used 23 BE_CS O Chip select signal output to the CPU 24 SIN I Serial data input terminal when data writing to internal ROM Not used 25 SOUT O Serial data output terminal when data writing to internal ROM Not used 26 SCLK I Serial data transfer clock signal input terminal when data writing to internal ROM Not used 27 232COUT O Transmit data output terminal for RS-232C Not used 28 232CIN I Receive data input terminal for RS-232C Not used 29 DSENS_OUT O Disc sensor signal output terminal for the adjustment 30 HH_OUT O Signal output terminal for the adjustment 31 SIRCS I Remote control signal input from the remote control receiver 32 NC O Not used 33 BE_BUSY I Busy signal input from the CPU 34 BE_RST O Reset signal output to the flash memories, CPU and D/A converter "L": reset 35 EVSS - Ground terminal 36 EVDD - Power supply terminal (+3.3V) 37 DDC_SDA I/O I2C data bus terminal Not used 38 DDC_SCL O I2C bus clock signal output terminal Not used 39 TBM+ O Table motor drive signal output terminal "H": motor on 40 TBM- O Table motor drive signal output terminal "H": motor on 41 to 44 NC O Not used 45 BE_TXD O UART transmit data output to the CPU 46 BE_RXD I UART receive data input from the CPU 47 DRM+ O Door motor drive signal output terminal "H": motor on 48 DRM- O Door motor drive signal output terminal "H": motor on 49 LDM+ O Loading motor drive signal output terminal "H": motor on 50 LDM- O Loading motor drive signal output terminal "H": motor on www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 84 DVP-CX995V Pin No. Pin Name I/O Description 51 PWM_CTRL O PWM control signal output terminal Not used 52 TSENS1 I Table address sensor signal (1) input terminal 53 TSENS3 I Table address sensor signal (3) input terminal 54 KBDIN I Keyboard data input terminal 55 VIDEO_OFF O Power on/off control signal output terminal for video section Not used 56 FLDSDATA O Serial data output to the FL driver 57 FLDSCLK O Serial data transfer clock signal output to the FL driver 58 KBCIN I Keyboard clock signal input terminal 59 TSENS2 I Table address sensor signal (2) input terminal 60 TSENS4 I Table address sensor signal (4) input terminal 61 FLDRST O Reset signal output to the FL driver "L": reset 62 FLDCS O Chip select signal output to the FL driver 63 FLHS O Output terminal for data writing to the flash memory 64 CLKOUT O Clock signal output terminal Not used 65 HDMI _INT O Interrupt request signal output terminal Not used 66 KBCOUT O Keyboard disable signal output terminal "H": stop 67 KBDOUT O Keyboard disable signal output terminal "H": stop 68 AMUTE O Audio muting on/off control signal output terminal "L": muting on 69 VMUTE O Video muting on/off control signal output to the video amplifier "L": muting on 70 P_CONT O Main power on/off control signal output terminal "H": power on 71 BVSS - Ground terminal 72 BVDD - Power supply terminal (+3.3V) 73 LED0 O LED drive signal output for HDMI indicator "H": LED on 74 LED1 O LED drive signal output for SA-CD indicator "H": LED on 75 LED2 O LED drive signal output for MULTI CHANNEL indicator "H": LED on 76 LED3 O LED drive signal output for FL OFF indicator "H": LED on 77 LED4 O LED drive signal output terminal Not used 78 FLMD1 I Flash memory data write mode control signal input terminal 79 LED7 O LED drive signal output for table illumination "H": LED on 80 NC O Not used 81 FL_CTRL O Flash memory data write mode control signal output terminal 82 +5V_CONT O Power on/off control signal output terminal for HDMI section (+5V) Not used 83 TMODE_SW O Test mode on/off control signal output to the CPU "H": test mode on 84 TMODE_IN I Test mode on/off control signal input terminal "L": normal mode, "H": test mode Fixed at "L" in this set 85 NO_INIT I No initialize mode setting terminal for mechanism "L": normal mode, "H": No initialize mode (normally at "L") 86 to 88 NC O Not used 89 LED5 O LED drive signal output for DISC CHANGE indicator "H": LED on 90 LED6 O LED drive signal output for DISC SEARCH indicator "H": LED on 91 LD_SW I Loading in/out detect switch and table lock detect switch input terminal (A/D input) 92 DR_SW I Door open/close detect switch and pop up/down detect switch input terminal (A/D input) 93 SIRCS MODE I Remote commander category code selection signal input terminal Not used 94 DSENS_IN I Disc sensor analog signal input terminal 95 PON_CHECK I +3.3V voltage monitor input terminal 96 MODEL_SEL I Model setting terminal Fixed at "L" in this set 97 SELF_CHECK I Self-diagnosis mode selection signal input terminal (normally at "H") 98 to 100 KEY4 to KEY2 I Front panel keys input terminal (A/D input) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 85 DVP-CX995V MB BOARD IC401 SAA7893HL (SACD MEDIA PLAYER) Pin No. Pin Name I/O Description 1 H_A1 I Address signal input from the CPU 2, 3 H_DQ15, H_DQ14 I/O Two-way data bus with the CPU 4 GND_IO1 - Ground terminal 5 to 9 H_DQ13 to H_DQ9 I/O Two-way data bus with the CPU 10 VCC_IO1 - Power supply terminal (+3.3V) 11 to 16 H_DQ8 to H_DQ3 I/O Two-way data bus with the CPU 17 GND_IO2 - Ground terminal 18 H_PROCCLOCK I 27MHz clock signal input terminal 19 VCC_CORE1 - Power supply terminal (+1.8V) 20 GND_CORE1 - Ground terminal 21 SYS_CLK I 27MHz clock signal input terminal 22, 23 H_DQ2, H_DQ1 I/O Two-way data bus with the CPU 24 H_CSN I Chip select signal input from the CPU 25 H_DQ0 I/O Two-way data bus with the CPU 26 H_RWN I Read/write selection signal input from the CPU "L": read, "H": write 27 H_WAIT O Chip wait signal output to the CPU 28 H_IRQN O Interrupt request signal output to the CPU 29 AUD_CLK I Master clock signal input from the CPU 30 PCM_DCLK_IN I PCM data clock input terminal Not used 31 PCM_WCLK_IN I PCM word clock input terminal Not used 32 VDDA - Power supply terminal (+1.8V) 33 VSSA - Ground terminal 34 BIASIN I Bias current input terminal 35 AGCINP I RF (for SACD) signal input from the DVD interface 36 ADCREFL I ADC decoupling terminal 37 VCC_IO7 - Power supply terminal (+3.3V) 38 GND_IO7 - Ground terminal 39 PCM_CELF_IN I PCM data (for center or LFE) input terminal Not used 40 PCM_LERI_IN I PCM data (for L-ch or R-ch) input terminal Not used 41 PCM_LSRS_IN I PCM data (for surround L-ch or surround R-ch) input terminal Not used 42 B_FLAG/SERR I I2S bus flag input from the CPU 43 B_SYNC/SYNC I Sector sync signal or absolute time sync signal input from the CPU 44 B_WCLK/SENB I I2S bus word clock signal input from the CPU 45 B_DATA/BE_DAT0 I I2S bus data input from the CPU 46 B_BCLK/SDCLK I I2S bus clock signal input from the CPU 47 UDE_REQ I Request signal input terminal Not used 48 DATA_REQ O Request signal output terminal Not used 49 to 55 BE_DAT1 to BE_DAT7 I Parallel data input terminal Not used 56 TRST I Reset signal input terminal (for JTAG) 57 TMS I Mode selection signal input terminal (for JTAG) 58 VCC_IO2 - Power supply terminal (+3.3V) 59 TDO O Data output terminal (for JTAG) 60 TDI I Data input terminal (for JTAG) 61 TCK I Clock signal input terminal (for JTAG) 62 H_SEL0 I Host selection signal input terminal Fixed at "L" in this set www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 86 DVP-CX995V Pin No. Pin Name I/O Description 63 H_SEL1 I Host selection signal input terminal Fixed at "H" in this set 64 to 68 D_ADDR1 to D_ADDR5 O Address signal output to the SD-RAM 69 GND_IO3 - Ground terminal 70 to 75 D_ADDR0, D_ADDR6 to D_ADDR8, D_ADDR10, D_ADDR13 O Address signal output to the SD-RAM 76 VCC_IO3 - Power supply terminal (+3.3V) 77 to 79 D_ADDR9, D_ADDR11, D_ADDR12 O Address signal output to the SD-RAM 80 D_WEN O Write enable signal output to the SD-RAM 81 D_RASN O Row address signal output to the SD-RAM 82 D_CASN O Column address signal output to the SD-RAM 83 GND_IO4 - Ground terminal 84 GND_CORE2 - Ground terminal 85 VCC_CORE2 - Power supply terminal (+1.8V) 86 D_CLK O Clock signal output to the SD-RAM 87 D_DQ5 I/O Two-way data bus with the SD-RAM 88 D_UDQM O Write mask signal output to the SD-RAM (upper byte) 89 D_LDQM O Write mask signal output to the SD-RAM (lower byte) 90, 91 D_DQ7, D_DQ8 I/O Two-way data bus with the SD-RAM 92 VCC_IO4 - Power supply terminal (+3.3V) 93 to 98 D_DQ4, D_DQ6, D_DQ9 to D_DQ11 I/O Two-way data bus with the SD-RAM 99 GND_IO5 - Ground terminal 100 to 105 D_DQ0 to D_DQ2, D_DQ12 to D_DQ14 I/O Two-way data bus with the SD-RAM 106 VCC_IO5 - Power supply terminal (+3.3V) 107 D_DQ15 I/O Two-way data bus with the SD-RAM 108 DSD_PCM_0 O DSD data (for front L-ch) output to the D/A converter 109 DSD_PCM_1 O DSD data (for front R-ch) output to the D/A converter 110 DSD_PCM_2 O DSD data (for center) output to the D/A converter 111 DSD_PCM_3 O DSD data (for woofer) output to the D/A converter 112 GND_IO5 - Ground terminal 113 DSD_PCM_4 O DSD data (for rear L-ch) output to the D/A converter 114 DSD_PCM_5 O DSD data (for rear R-ch) output to the D/A converter 115, 116 DSD_PCM_6, DSD_PCM_7 O DSD data output terminal Not used 117 DSD_PCM_8 O DSD clock signal output to the D/A converter 118 VCC_IO6 - Power supply terminal (+3.3V) 119 DSD_PCM_10 O DSD data output terminal Not used 120 DSD_PCM_9 O DSD data (for R-ch) output to the D/A converter 121 DSD_PCM_11 O DSD data (for L-ch) output to the D/A converter 122 RESETN I Reset signal input from the CPU "L": reset 123 H_A_SEL I Address signal input from the CPU 124 to 128 H_A6 to H_A2 I Address signal input from the CPU www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 87 DVP-CX995V AV BOARD IC401 CXD9866R (INTERLACE/PROGRESSIVE CONVERTER) Pin No. Pin Name I/O Description 1 to 3 TEST0 to TEST2 I Input terminal for the test 4 ALSB I I2C slave address setting terminal 5 SDA I/O I2C two-way data bus with the DVD interface, CPU, video D/A converter and HDMI transmitter 6 SCL I I2C bus clock signal input from the CPU 7 TEST3 I Input terminal for the test 8 NRST I Reset signal input from the CPU "L": reset 9 TEST4 I Input terminal for the test 10 CLKI I 27 MHz clock signal input from the CPU 11 TEST5 I Input terminal for the test 12 AVS1 - Ground terminal (analog system) 13 AVD1 - Power supply terminal (+3.3V) (analog system) 14 CPO O Charge pump output terminal 15 VCI I VCO input terminal 16 AVS2 - Ground terminal (analog system) 17 AVD2 - Power supply terminal (+3.3V) (analog system) 18 NTEST I Input terminal for the test 19 VI I Vertical synchronize signal input terminal Not used 20 HI I Horizontal synchronize signal input terminal Not used 21, 22 SI0, SI1 I Digital video signal input terminal Not used 23 to 30 SI2 to SI9 I Digital video signal input from the CPU 31 VSS - Ground terminal (digital system) 32 VDDI - Power supply terminal (+1.8V) (for core) 33 VDDE - Power supply terminal (+3.3V) (for I/O) 34 to 43 CO9 to CO0 O CB (component video) and CR (component video) signal output to the video D/A converter 44 VSS - Ground terminal (digital system) 45 VDDI - Power supply terminal (+1.8V) (for core) 46 VDDE - Power supply terminal (+3.3V) (for I/O) 47 to 56 YO9 to YO0 O Y (component video) signal output to the video D/A converter 57 VSS - Ground terminal (digital system) 58 VDDI - Power supply terminal (+1.8V) (for core) 59 CLKO O 27 MHz clock signal output to the video D/A converter 60 VDDE - Power supply terminal (+3.3V) (for I/O) 61 to 70 SO9 to SO0 O Video signal output to the video D/A converter 71 TEST6 I Input terminal for the test 72 HO O Horizontal synchronize signal output terminal Not used 73 VO O Vertical synchronize signal output terminal Not used 74 FILM O Film detection flag output terminal Not used 75 VDDI - Power supply terminal (+1.8V) (for core) 76 VSS - Ground terminal (digital system) 77 VDDE - Power supply terminal (+3.3V) (for I/O) 78 AVSP - Ground terminal (analog system) 79 AVDP - Power supply terminal (+3.3V) (analog system) 80 VSS - Ground terminal (digital system) 81 VDDE - Power supply terminal (+3.3V) (for I/O) 82 VDDI - Power supply terminal (+1.8V) (for core) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 88 DVP-CX995V Pin No. Pin Name I/O Description 83 MCLK O 108 MHz clock signal output to the SD-RAM 84 VSS - Ground terminal (digital system) 85 to 88 MD19 to MD16 I/O Two-way data bus terminal Not used 89 VDDI - Power supply terminal (+1.8V) (for core) 90 VSS - Ground terminal (digital system) 91 VDDE - Power supply terminal (+3.3V) (for I/O) 92 to 98 MA0 to MA6 O Address signal output to the SD-RAM 99 VDDE - Power supply terminal (+3.3V) (for I/O) 100 VSS - Ground terminal (digital system) 101 to 105 MA7 to MA11 O Address signal output to the SD-RAM 106 RAS O Row address signal output to the SD-RAM 107 DQM O Write mask signal output to the SD-RAM 108 CAS O Column address signal output to the SD-RAM 109 WE O Write enable signal output to the SD-RAM 110 VDDE - Power supply terminal (+3.3V) (for I/O) 111 VSS - Ground terminal (digital system) 112 VDDI - Power supply terminal (+1.8V) (for core) 113 to 120 MD4 to MD11 I/O Two-way data bus with the SD-RAM 121 VDDE - Power supply terminal (+3.3V) (for I/O) 122 VSS - Ground terminal (digital system) 123 to 130 MD0 to MD3, MD12 to MD15 I/O Two-way data bus with the SD-RAM 131 VDDI - Power supply terminal (+1.8V) (for core) 132 VSS - Ground terminal (digital system) 133 VDDE - Power supply terminal (+3.3V) (for I/O) 134 QV O Vertical synchronize signal output to the HDMI transmitter 135 QH O Horizontal synchronize signal output to the HDMI transmitter 136 QDE O Data enable signal output to the HDMI transmitter 137 VSS - Ground terminal (digital system) 138 to 141 QB0 to QB3 O RGB (blue) signal output to the HDMI transmitter 142 VDDE - Power supply terminal (+3.3V) (for I/O) 143 to 146 QB4 to QB7 O RGB (blue) signal output to the HDMI transmitter 147 VSS - Ground terminal (digital system) 148 QCLK O Clock signal output to the HDMI transmitter 149 VDDI - Power supply terminal (+1.8V) (for core) 150 VDDE - Power supply terminal (+3.3V) (for I/O) 151 to 154 QG0 to QG3 O RGB (green) signal output to the HDMI transmitter 155 VSS - Ground terminal (digital system) 156 VDDE - Power supply terminal (+3.3V) (for I/O) 157 to 160 QG4 to QG7 O RGB (green) signal output to the HDMI transmitter 161 VDDI - Power supply terminal (+1.8V) (for core) 162 VSS - Ground terminal (digital system) 163 VDDE - Power supply terminal (+3.3V) (for I/O) 164 to 167 QR0 to QR3 O RGB (red) signal output to the HDMI transmitter 168 VSS - Ground terminal (digital system) 169 VDDE - Power supply terminal (+3.3V) (for I/O) 170 to 173 QR4 to QR7 O RGB (red) signal output to the HDMI transmitter www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 89 DVP-CX995V Pin No. Pin Name I/O Description 174 VDDI - Power supply terminal (+1.8V) (for core) 175 VDDE - Power supply terminal (+3.3V) (for I/O) 176 VSS - Ground terminal (digital system) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 90 DVP-CX995V SECTION 8 EXPLODED VIEWS Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 1 A-1132-163-A MB BOARD, COMPLETE 2 1-830-199-11 WIRE, FLAT TYPE (33 CORE) ◊ 3 A-1126-999-A AV BOARD, COMPLETE (for SERVICE) 4 1-830-198-11 WIRE, FLAT TYPE (31 CORE) 5 1-830-200-11 WIRE, FLAT TYPE (29 CORE) 6 3-363-099-02 SCREW (CASE 3 TP2) 7 4-246-970-11 CASE 9 3-077-331-21 +BV3 (3-CR) 10 3-531-576-01 RIVET #1 7-685-646-79 SCREW +BVTP 3X8 TYPE2 IT-3 #2 7-685-872-09 SCREW +BVTT 3X8 (S) 8-1. OVERALL SECTION • Items marked “*” are not stocked since they are seldom required for routine service. Some delay should be anticipated when ordering these items. • The mechanical parts with no reference number in the exploded views are not supplied. • Accessories are given in the last of the electrical parts list. NOTE: • -XX and -X mean standardized parts, so they may have some difference from the original one. • Color Indication of Appearance Parts Example: KNOB, BALANCE (WHITE) . . . (RED) ↑ ↑ Parts Color Cabinet's Color Les composants identifiés par une marque 0 sont critiquens pour la sécurité. Ne les remplacer que par une pièce portant le numéro spécifié. The components identified by mark 0 or dotted line with mark 0 are critical for safety. Replace only with part number specified. 1 4 2 5 10 6 6 6 6 7 9 3 #1 not supplied not supplied not supplied front panel section not supplied not supplied not supplied not supplied not supplied power block section #1 #1 not supplied #1 #1 #2 #1 #1 #1 #1 #1 #1 #1 #1 #1 #1 #1 not supplied Ver. 1.1 ◊ Please refer to “NOTE OF HANDLING THE AV BOARD (Part No. A-1126-999-A)” on the service note (Page 4) for handling of this board. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 91 DVP-CX995V 8-2. FRONT PANEL SECTION Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 51 4-246-979-01 KNOB (AMS) 52 4-977-358-01 CUSHION 53 X-2023-793-1 PANEL ASSY, FRONT 54 4-985-553-21 CUSHION 56 1-828-394-11 WIRE (FLAT TYPE) (25 CORE) 57 3-087-053-01 +BVTP2.6 (3CR) 58 A-1076-700-A PANEL-L BOARD, COMPLETE 60 A-1076-688-A PANEL-R BOARD, COMPLETE 61 X-2055-398-1 KNOB (CUR) ASSY 51 52 53 56 57 57 54 57 57 57 57 57 58 60 61 not supplied not supplied (KEY BOARD board) not supplied not supplied www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 92 DVP-CX995V 8-3. POWER BLOCK SECTION Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 101 4-226-841-02 COVER (PT) 0102 1-468-894-11 REGULATOR, SWITCHING 104 4-226-876-21 COVER (CDM) 0105 1-783-820-31 CORD, POWER * 106 3-703-244-00 BUSHING (2104), CORD 107 4-250-786-01 LOCKING WIRE SADDLE 108 1-500-386-11 FILTER, CLAMP (FERRITE CORE) #1 7-685-646-79 SCREW +BVTP 3X8 TYPE2 IT-3 101 102 108 104 105 106 not supplied not supplied not supplied not supplied not supplied table section #1 #1 #1 #1 #1 #1 #1 #1 #1 #1 107 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 93 DVP-CX995V 8-4. TABLE SECTION Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 151 X-2023-792-1 DOOR ASSY 152 4-226-834-02 COVER (TABLE) 153 X-4952-500-2 TABLE (400) ASSY 154 4-226-833-06 GUIDE (DOOR) 155 4-215-968-01 WINDOW (INTERNAL ILLUMINATION) 157 3-701-447-21 WASHER, 10 158 A-1076-698-A DRIVER BOARD, COMPLETE 159 3-356-601-13 SCREW, STEP 160 3-703-136-01 SCREW (M3X14) #1 7-685-646-79 SCREW +BVTP 3X8 TYPE2 IT-3 #4 7-685-903-11 SCREW +PTPWH 3X6 (TYPE2) 151 159 152 153 154 155 160 157 158 chassis section base (door) section CD/DVD mechanism deck section-1 (pop-up block) #1 #1 #1 #1 #1 #4 not supplied (LED board) not supplied www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 94 DVP-CX995V 8-5. CHASSIS SECTION Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 201 3-703-249-02 SCREW, S TIGHT, +PTTWH 3X6 204 4-225-873-01 HOLDER (TABLE SENSOR 400) 206 4-216-096-02 SCREW (T1), STEP 207 4-216-088-02 GUIDE (DISC) 208 4-216-089-02 SHAFT (CENTER) 210 4-216-093-01 ROLLER 211 4-216-092-03 HOLDER (ROLLER) 212 4-965-822-01 FOOT 213 X-2022-049-1 FOOT ASSY #1 7-685-646-79 SCREW +BVTP 3X8 TYPE2 IT-3 #5 7-685-645-79 SCREW +BVTP 3X6 TYPE2 N-S #7 7-682-948-01 SCREW +PSW 3X8 #8 7-685-871-01 SCREW +BVTT 3X6 (S) #1 #7 #1 #1 #1 212 212 213 207 211 210 not supplied CD/DVD mechanism deck section-2 (pulley block) 208 204 206 #7 not supplied not supplied (SENSOR board) not supplied (D. SENS IN board) not supplied (D. SENS OUT board) not supplied not supplied #1 #8 #5 #1 #1 #5 #5 #5 201 201 #7 not supplied www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 95 DVP-CX995V 8-6. BASE (DOOR) SECTION Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 251 4-226-827-02 BASE (DOOR DRIVING) 252 4-216-093-01 ROLLER 253 4-226-832-01 LEVER (PU JOINT) 254 4-218-254-21 SCREW (M2.6), +PTPWH 255 4-219-326-01 BELT (DIA. 42X1.2) 256 4-226-828-02 GEAR (CAM) 257 4-226-829-01 GEAR (PULLEY) 258 4-226-831-01 GEAR (B) 259 4-226-830-01 GEAR (A) 260 4-955-234-61 PULLEY (MOTOR CDM) 262 3-087-053-01 +BVTP2.6 (3CR) M603 1-541-632-12 MOTOR, DC (DOOR) #1 7-685-646-79 SCREW +BVTP 3X8 TYPE2 IT-3 251 252 252 260 253 254 254 254 254 254 256 255 257 258 259 262 M603 not supplied (DOOR SW board) not supplied (DOOR MOTOR board) #1 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 96 DVP-CX995V 8-7. CD/DVD MECHANISM DECK SECTION-1 (POP-UP BLOCK) Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 301 4-216-100-02 HOLDER (POP-UP) 302 4-216-103-01 SPRING (POP-UP), COMPRESSION 303 3-701-441-21 WASHER 304 4-998-716-01 SCREW, BU FITTING 305 4-216-102-01 SHAFT (POP-UP FULCRUM) 306 4-216-104-01 SPRING (POP-UP), TENSION 307 4-228-352-01 LEVER (POP-UP 400) 308 4-216-099-02 SLIDER (POP-UP) #6 7-624-106-04 STOP RING 3.0, TYPE -E #6 #6 301 302 302 303 303 304 305 306 307 308 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 97 DVP-CX995V 8-8. CD/DVD MECHANISM DECK SECTION-2 (PULLEY BLOCK) Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 351 4-245-983-01 PULLEY (A) 352 4-216-082-11 HOLDER (MAGNET), TORSION 353 4-245-984-01 PULLEY (B) 354 3-701-441-21 WASHER 355 4-216-081-01 SPRING (MG), TORSION 356 3-701-446-21 WASHER, 8 not supplied 352 351 354 355 356 CD/DVD mechanism deck section-3 (lever, holder block) base unit section (DVBU65) 353 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 98 DVP-CX995V 8-9. CD/DVD MECHANISM DECK SECTION-3 (LEVER, HOLDER BLOCK) Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 401 X-4952-499-1 LEVER (LOCK 400) ASSY 402 4-216-067-01 SPRING (CLAMP), COMPRESSION 403 3-701-441-21 WASHER 404 X-4952-501-1 HOLDER (DISC L400) ASSY 405 X-4952-502-1 HOLDER (DISC R400) ASSY 406 4-225-868-01 SHAFT (CLAMP 400) 407 3-325-697-21 WASHER 408 4-216-076-11 HOLDER (R) 409 4-216-077-01 SPRING (HOLDER FR), TORSION 410 4-225-871-03 HOLDER (F400) 411 X-4950-900-1 BRACKET (LEVER) ASSY 412 4-216-080-01 SPRING (LIMITTER), TORSION 413 4-216-079-02 LIMITTER (LEVER) 414 4-216-078-01 LEVER (LOADING) 415 4-998-716-01 SCREW, BU FITTING #1 7-685-646-79 SCREW +BVTP 3X8 TYPE2 IT-3 #6 7-624-106-04 STOP RING 3.0, TYPE -E 404 405 403 402 401 408 409 407 411 414 407 412 413 415 410 402 403 406 #6 #1 #6 CD/DVD mechanism deck section-4 (gear, motor block) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 99 DVP-CX995V 8-10. CD/DVD MECHANISM DECK SECTION-4 (GEAR, MOTOR BLOCK) Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 451 4-225-865-01 SLIDER (400) 453 X-4952-503-1 LEVER (FULCRUM 400) ASSY 456 A-4672-676-B CAM ASSY 457 4-225-876-01 BELT (400) 458 4-225-870-01 PULLEY (400) 459 4-216-057-01 GEAR (CENTER 2) 460 4-216-058-01 GEAR (CENTER) 461 3-087-053-01 +BVTP2.6 (3CR) 463 4-225-869-01 GEAR (TABLE 400) M601 A-4672-895-A MOTOR (400) ASSY (TABLE) M602 A-4672-895-A MOTOR (400) ASSY (LOADING) #1 7-685-646-79 SCREW +BVTP 3X8 TYPE2 IT-3 #3 7-685-648-79 SCREW +BVTP 3X12 TYPE2 IT-3 #7 7-682-948-01 SCREW +PSW 3X8 457 458 #3 #7 #3 459 456 460 458 453 451 453 457 461 460 463 #1 not supplied not supplied (LOCK SW board) not supplied (LOADING SW board) not supplied (LOADING MOTOR board) M601 #1 M602 not supplied www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 100 DVP-CX995V 8-11. BASE UNIT SECTION (DVBU65) Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 0501 A-1109-165-A OPTICAL PICK-UP (DBU-3) (SERVICE ASSY) (including spindle motor) 502 4-981-923-01 SCREW (M), STEP 503 3-057-023-11 INSULATOR (RB) 504 X-2023-735-1 HOLDER, DBU400 ASSY 505 1-824-106-51 CABLE, FLEXIBLE FLAT (0.5mm pitch) 506 3-087-053-01 +BVTP2.6 (3CR) 501 (including spindle motor) 502 502 502 503 503 503 504 505 506 not supplied (RF TRANSLATION board) not supplied (spindle motor) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 101 DVP-CX995V SECTION 9 ELECTRICAL PARTS LIST Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark ◊ A-1126-999-A AV BOARD, COMPLETE (for SERVICE) ******************* < CAPACITOR > C101 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C102 1-126-204-11 ELECT CHIP 47uF 20% 16V C103 1-126-204-11 ELECT CHIP 47uF 20% 16V C104 1-126-204-11 ELECT CHIP 47uF 20% 16V C105 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V C106 1-126-204-11 ELECT CHIP 47uF 20% 16V C107 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C108 1-126-204-11 ELECT CHIP 47uF 20% 16V C109 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C201 1-130-478-00 MYLAR 0.0039uF 5% 50V C202 1-135-580-11 MYLAR 330PF 5% 50V C203 1-130-479-00 MYLAR 0.0047uF 5% 50V C204 1-135-580-11 MYLAR 330PF 5% 50V C205 1-126-947-11 ELECT 47uF 20% 35V C207 1-110-339-11 MYLAR 220PF 5% 50V C211 1-130-478-00 MYLAR 0.0039uF 5% 50V C212 1-135-580-11 MYLAR 330PF 5% 50V C213 1-130-479-00 MYLAR 0.0047uF 5% 50V C214 1-135-580-11 MYLAR 330PF 5% 50V C215 1-126-947-11 ELECT 47uF 20% 35V C217 1-110-339-11 MYLAR 220PF 5% 50V C221 1-130-478-00 MYLAR 0.0039uF 5% 50V C222 1-135-580-11 MYLAR 330PF 5% 50V C223 1-130-479-00 MYLAR 0.0047uF 5% 50V C224 1-135-580-11 MYLAR 330PF 5% 50V C225 1-126-947-11 ELECT 47uF 20% 35V C227 1-110-339-11 MYLAR 220PF 5% 50V C231 1-130-478-00 MYLAR 0.0039uF 5% 50V C232 1-135-580-11 MYLAR 330PF 5% 50V C233 1-130-479-00 MYLAR 0.0047uF 5% 50V C234 1-135-580-11 MYLAR 330PF 5% 50V C235 1-126-947-11 ELECT 47uF 20% 35V C237 1-110-339-11 MYLAR 220PF 5% 50V C241 1-130-478-00 MYLAR 0.0039uF 5% 50V C242 1-135-580-11 MYLAR 330PF 5% 50V C243 1-130-479-00 MYLAR 0.0047uF 5% 50V C244 1-135-580-11 MYLAR 330PF 5% 50V C245 1-126-947-11 ELECT 47uF 20% 35V C247 1-110-339-11 MYLAR 220PF 5% 50V C251 1-130-478-00 MYLAR 0.0039uF 5% 50V C252 1-135-580-11 MYLAR 330PF 5% 50V C253 1-130-479-00 MYLAR 0.0047uF 5% 50V C254 1-135-580-11 MYLAR 330PF 5% 50V C255 1-126-947-11 ELECT 47uF 20% 35V C257 1-110-339-11 MYLAR 220PF 5% 50V C261 1-130-478-00 MYLAR 0.0039uF 5% 50V C262 1-135-580-11 MYLAR 330PF 5% 50V C263 1-130-479-00 MYLAR 0.0047uF 5% 50V C264 1-135-580-11 MYLAR 330PF 5% 50V C265 1-126-947-11 ELECT 47uF 20% 35V C267 1-110-339-11 MYLAR 220PF 5% 50V C271 1-130-478-00 MYLAR 0.0039uF 5% 50V C272 1-135-580-11 MYLAR 330PF 5% 50V C273 1-130-479-00 MYLAR 0.0047uF 5% 50V C274 1-135-580-11 MYLAR 330PF 5% 50V C275 1-126-947-11 ELECT 47uF 20% 35V C277 1-110-339-11 MYLAR 220PF 5% 50V C301 1-126-947-11 ELECT 47uF 20% 35V C302 1-126-947-11 ELECT 47uF 20% 35V C305 1-126-947-11 ELECT 47uF 20% 35V C306 1-126-947-11 ELECT 47uF 20% 35V C309 1-126-947-11 ELECT 47uF 20% 35V C310 1-126-947-11 ELECT 47uF 20% 35V C313 1-126-947-11 ELECT 47uF 20% 35V C314 1-126-947-11 ELECT 47uF 20% 35V C317 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C318 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C321 1-126-960-11 ELECT 1uF 20% 50V C322 1-126-960-11 ELECT 1uF 20% 50V C323 1-126-960-11 ELECT 1uF 20% 50V C324 1-126-767-11 ELECT 1000uF 20% 16V C341 1-126-947-11 ELECT 47uF 20% 35V C342 1-126-947-11 ELECT 47uF 20% 35V C344 1-126-947-11 ELECT 47uF 20% 35V C351 1-126-947-11 ELECT 47uF 20% 35V C352 1-126-947-11 ELECT 47uF 20% 35V C353 1-126-924-11 ELECT 330uF 20% 10V C354 1-126-947-11 ELECT 47uF 20% 35V C355 1-126-947-11 ELECT 47uF 20% 35V C356 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C357 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C358 1-126-947-11 ELECT 47uF 20% 35V C371 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V NOTE: • Due to standardization, replacements in the parts list may be different from the parts specified in the diagrams or the components used on the set. • -XX and -X mean standardized parts, so they may have some difference from the original one. • RESISTORS All resistors are in ohms. METAL: Metal-film resistor. METAL OXIDE: Metal oxide-film resistor. F: nonflammable • Items marked “*” are not stocked since they are seldom required for routine service. Some delay should be anticipated when ordering these items. • SEMICONDUCTORS In each case, u: µ, for example: uA... : µA... uPA... : µPA... uPB... : µPB... uPC... : µPC... uPD... : µPD... • CAPACITORS uF: µF • COILS uH: µH AV Les composants identifiés par une marque 0 sont critiquens pour la sécurité. Ne les remplacer que par une pièce portant le numéro spécifié. The components identified by mark 0 or dotted line with mark 0 are critical for safety. Replace only with part number specified. When indicating parts by reference number, please include the board. Ver. 1.1 ◊ Please refer to “NOTE OF HANDLING THE AV BOARD (Part No. A-1126-999-A)” on the service note (Page 4) for handling of this board. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 102 DVP-CX995V C372 1-104-665-11 ELECT 100uF 20% 25V C373 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C374 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C375 1-104-665-11 ELECT 100uF 20% 25V C376 1-104-665-11 ELECT 100uF 20% 25V C377 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C378 1-104-665-11 ELECT 100uF 20% 25V C379 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C380 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C381 1-104-665-11 ELECT 100uF 20% 25V C382 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C383 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C384 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C385 1-104-665-11 ELECT 100uF 20% 25V C386 1-162-962-11 CERAMIC CHIP 470PF 10% 50V C401 1-126-206-11 ELECT CHIP 100uF 20% 6.3V C402 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C403 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C404 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C405 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C406 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C407 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C408 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C409 1-100-159-91 CERAMIC CHIP 22uF 10% 6.3V C410 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C411 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C412 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C413 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C414 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C415 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C416 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C417 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C418 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C419 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C420 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C421 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C422 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C423 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C424 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C425 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C426 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C427 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C428 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C429 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C430 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C431 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C432 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C433 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C434 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C435 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C436 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C437 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C438 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C439 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C440 1-128-934-11 CERAMIC CHIP 0.33uF 20% 10V C441 1-164-677-11 CERAMIC CHIP 0.033uF 10% 16V C443 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C444 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C445 1-126-206-11 ELECT CHIP 100uF 20% 6.3V C446 1-126-208-21 ELECT CHIP 47uF 20% 4V C447 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C448 1-164-315-11 CERAMIC CHIP 470PF 5% 50V C449 1-164-315-11 CERAMIC CHIP 470PF 5% 50V C450 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C451 1-164-315-11 CERAMIC CHIP 470PF 5% 50V C452 1-164-315-11 CERAMIC CHIP 470PF 5% 50V C453 1-164-315-11 CERAMIC CHIP 470PF 5% 50V C454 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C455 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C456 1-164-315-11 CERAMIC CHIP 470PF 5% 50V C457 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C458 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C459 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C460 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C461 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C462 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C463 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C464 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C465 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C466 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C467 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C468 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C469 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C470 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C471 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C472 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C500 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V C501 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V C502 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V C503 1-126-206-11 ELECT CHIP 100uF 20% 6.3V C504 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V C505 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V C506 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V C507 1-164-173-11 CERAMIC CHIP 0.0039uF 10% 50V C508 1-164-733-11 CERAMIC CHIP 820PF 10% 50V C509 1-127-956-21 FILM CHIP 0.1uF 5% 16V C510 1-127-956-21 FILM CHIP 0.1uF 5% 16V C511 1-126-206-11 ELECT CHIP 100uF 20% 6.3V C512 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V C513 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C514 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V C515 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C516 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C517 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C518 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C519 1-126-206-11 ELECT CHIP 100uF 20% 6.3V C600 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C601 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C602 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C603 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C604 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C605 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C606 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C607 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C608 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V AV www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 103 DVP-CX995V C609 1-100-159-91 CERAMIC CHIP 22uF 10% 6.3V C610 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V C611 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V C612 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C613 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C614 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C615 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C616 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C617 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C618 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C619 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C620 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C621 1-100-159-91 CERAMIC CHIP 22uF 10% 6.3V C622 1-100-159-91 CERAMIC CHIP 22uF 10% 6.3V C623 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C624 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C625 1-124-778-00 ELECT CHIP 22uF 20% 6.3V C626 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C627 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C628 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V C629 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C630 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C631 1-126-208-21 ELECT CHIP 47uF 20% 4V C632 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V C633 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C634 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C635 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C636 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C637 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V C638 1-126-205-11 ELECT CHIP 47uF 20% 6.3V < CONNECTOR > * CN301 1-564-716-11 PIN, CONNECTOR (SMALL TYPE) 14P * CN302 1-564-711-11 PIN, CONNECTOR (SMALL TYPE) 9P * CN303 1-564-705-11 PIN, CONNECTOR (SMALL TYPE) 3P * CN304 1-568-954-11 PIN, CONNECTOR 5P CN306 1-784-836-21 CONNECTOR, FFC (LIF (NON-ZIF)) 29P CN400 1-784-881-21 CONNECTOR, FFC (LIF (NON-ZIF)) 33P < DIODE > D101 8-719-053-18 DIODE 1SR154-400TE-25 D102 8-719-053-18 DIODE 1SR154-400TE-25 D103 8-719-071-15 DIODE HZM6.8ZWA1TL D104 8-719-071-15 DIODE HZM6.8ZWA1TL D105 8-719-071-15 DIODE HZM6.8ZWA1TL D106 8-719-071-15 DIODE HZM6.8ZWA1TL D301 8-719-914-43 DIODE DAN202K D351 8-719-988-61 DIODE 1SS355TE-17 D371 8-719-914-44 DIODE DAP202K D601 6-500-701-01 DIODE PGB1010603NR D602 6-500-701-01 DIODE PGB1010603NR D603 6-500-701-01 DIODE PGB1010603NR D604 6-500-701-01 DIODE PGB1010603NR D605 6-500-701-01 DIODE PGB1010603NR D606 6-500-701-01 DIODE PGB1010603NR D607 6-500-701-01 DIODE PGB1010603NR D608 6-500-701-01 DIODE PGB1010603NR < FERRITE BEAD/JUMPER RESISTOR > FB400 1-216-864-11 SHORT CHIP 0 FB600 1-414-921-11 INDUCTOR, FERRITE BEAD FB601 1-414-921-11 INDUCTOR, FERRITE BEAD FB602 1-414-921-11 INDUCTOR, FERRITE BEAD FB603 1-414-921-11 INDUCTOR, FERRITE BEAD FB604 1-414-921-11 INDUCTOR, FERRITE BEAD < EARTH TERMINAL > * G201 1-537-738-21 TERMINAL, EARTH * G202 1-537-738-21 TERMINAL, EARTH < IC/JACK/FET > IC101 8-759-662-86 IC NJM79M05DL1A (TE2) IC102 6-701-820-01 IC LA73053-TLM-E IC201 8-759-100-96 IC uPC4558G2 IC202 8-759-100-96 IC uPC4558G2 IC203 8-759-100-96 IC uPC4558G2 IC204 8-759-100-96 IC uPC4558G2 IC301 1-819-190-11 PLATE, JACK (PIN+OPTICAL OUT) (PCM/DTS/DOLBY DIGITAL, DIGITAL OUT) IC302 8-759-052-52 IC L78M05T-FA IC371 8-759-583-47 IC uPC2933T-E2 IC400 6-702-300-01 IC TK11118CSCL-G IC401 6-708-021-01 IC CXD9866R IC402 6-705-992-11 IC HY57V161610ETP-7DR IC500 6-701-079-01 IC ADV7300AKST IC501 6-702-301-01 IC TK11125CSCL-G IC502 8-759-583-47 IC uPC2933T-E2 IC600 (Not supplied) IC SII9030CTU-1.1 IC601 6-702-300-01 IC TK11118CSCL-G IC602 6-703-046-01 IC SN74LVC1G08DCKR IC603 6-705-337-01 IC TK11150CSCL-G IC604 6-702-302-01 IC TK11133CSCL-G IC605 6-550-014-01 FET SSM6N15FU (TE85R) < JACK > J101 1-694-484-21 TERMINAL, S (2P.V) (S VIDEO OUT) J102 1-815-361-11 JACK, PIN 3P (COMPONENT VIDEO OUT) J103 1-815-363-11 JACK, PIN (6P) (VIDEO LINE OUT) J201 1-793-482-11 JACK, PIN 6P (5.1CH OUTPUT) J600 1-818-086-41 HDMI CONNECTOR (HDMI OUT) < COIL > L101 1-412-060-11 INDUCTOR 22uH L102 1-412-060-11 INDUCTOR 22uH L351 1-419-387-21 INDUCTOR 100uH < IC LINK > PS371 1-532-637-00 IC LINK PS372 1-532-637-00 IC LINK < TRANSISTOR > Q103 8-729-027-46 TRANSISTOR DTC114YKA-T146 Q104 8-729-027-31 TRANSISTOR DTA124EKA-T146 Q201 8-729-046-97 TRANSISTOR 2SD1938 (F)-T (TX).SO AV www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 104 DVP-CX995V Q202 8-729-046-97 TRANSISTOR 2SD1938 (F)-T (TX).SO Q203 8-729-046-97 TRANSISTOR 2SD1938 (F)-T (TX).SO Q204 8-729-046-97 TRANSISTOR 2SD1938 (F)-T (TX).SO Q205 8-729-046-97 TRANSISTOR 2SD1938 (F)-T (TX).SO Q206 8-729-046-97 TRANSISTOR 2SD1938 (F)-T (TX).SO Q207 8-729-046-97 TRANSISTOR 2SD1938 (F)-T (TX).SO Q208 8-729-046-97 TRANSISTOR 2SD1938 (F)-T (TX).SO Q301 8-729-027-59 TRANSISTOR DTC144EKA-T146 Q302 8-729-027-53 TRANSISTOR DTC124TKA-T146 Q303 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX Q304 8-729-027-59 TRANSISTOR DTC144EKA-T146 Q305 8-729-027-53 TRANSISTOR DTC124TKA-T146 Q306 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX Q307 8-729-027-59 TRANSISTOR DTC144EKA-T146 Q308 8-729-027-53 TRANSISTOR DTC124TKA-T146 Q309 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX Q310 8-729-230-49 TRANSISTOR 2SC2712-YG Q351 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX Q352 8-729-230-49 TRANSISTOR 2SC2712-YG Q353 8-729-049-31 TRANSISTOR 2SB710A-RTX Q371 6-550-543-01 TRANSISTOR 2SD1766FT100QR Q372 8-729-027-23 TRANSISTOR DTA114EKA-T146 Q373 8-729-230-49 TRANSISTOR 2SC2712-YG Q374 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX < RESISTOR > R101 1-216-864-11 SHORT CHIP 0 R103 1-216-864-11 SHORT CHIP 0 R110 1-216-833-11 METAL CHIP 10K 5% 1/10W R111 1-216-807-11 METAL CHIP 68 5% 1/10W R112 1-216-807-11 METAL CHIP 68 5% 1/10W R113 1-216-807-11 METAL CHIP 68 5% 1/10W R114 1-216-807-11 METAL CHIP 68 5% 1/10W R115 1-216-807-11 METAL CHIP 68 5% 1/10W R116 1-216-807-11 METAL CHIP 68 5% 1/10W R117 1-216-807-11 METAL CHIP 68 5% 1/10W R118 1-216-807-11 METAL CHIP 68 5% 1/10W R119 1-216-807-11 METAL CHIP 68 5% 1/10W R129 1-216-864-11 SHORT CHIP 0 R132 1-216-864-11 SHORT CHIP 0 R201 1-218-845-11 METAL CHIP 820 0.5% 1/10W R202 1-218-847-11 METAL CHIP 1K 0.5% 1/10W R203 1-218-845-11 METAL CHIP 820 0.5% 1/10W R204 1-218-847-11 METAL CHIP 1K 0.5% 1/10W R205 1-218-855-11 METAL CHIP 2.2K 0.5% 1/10W R206 1-218-845-11 METAL CHIP 820 0.5% 1/10W R207 1-218-845-11 METAL CHIP 820 0.5% 1/10W R208 1-218-855-11 METAL CHIP 2.2K 0.5% 1/10W R209 1-218-887-11 METAL CHIP 47K 0.5% 1/10W R210 1-218-839-11 METAL CHIP 470 0.5% 1/10W R211 1-218-845-11 METAL CHIP 820 0.5% 1/10W R212 1-218-847-11 METAL CHIP 1K 0.5% 1/10W R213 1-218-845-11 METAL CHIP 820 0.5% 1/10W R214 1-218-847-11 METAL CHIP 1K 0.5% 1/10W R215 1-218-855-11 METAL CHIP 2.2K 0.5% 1/10W R216 1-218-845-11 METAL CHIP 820 0.5% 1/10W R217 1-218-845-11 METAL CHIP 820 0.5% 1/10W R218 1-218-855-11 METAL CHIP 2.2K 0.5% 1/10W R219 1-218-887-11 METAL CHIP 47K 0.5% 1/10W R220 1-218-839-11 METAL CHIP 470 0.5% 1/10W R221 1-218-845-11 METAL CHIP 820 0.5% 1/10W R222 1-218-847-11 METAL CHIP 1K 0.5% 1/10W R223 1-218-845-11 METAL CHIP 820 0.5% 1/10W R224 1-218-847-11 METAL CHIP 1K 0.5% 1/10W R225 1-218-855-11 METAL CHIP 2.2K 0.5% 1/10W R226 1-218-845-11 METAL CHIP 820 0.5% 1/10W R227 1-218-845-11 METAL CHIP 820 0.5% 1/10W R228 1-218-855-11 METAL CHIP 2.2K 0.5% 1/10W R229 1-218-887-11 METAL CHIP 47K 0.5% 1/10W R230 1-218-839-11 METAL CHIP 470 0.5% 1/10W R231 1-218-845-11 METAL CHIP 820 0.5% 1/10W R232 1-218-847-11 METAL CHIP 1K 0.5% 1/10W R233 1-218-845-11 METAL CHIP 820 0.5% 1/10W R234 1-218-847-11 METAL CHIP 1K 0.5% 1/10W R235 1-218-855-11 METAL CHIP 2.2K 0.5% 1/10W R236 1-218-845-11 METAL CHIP 820 0.5% 1/10W R237 1-218-845-11 METAL CHIP 820 0.5% 1/10W R238 1-218-855-11 METAL CHIP 2.2K 0.5% 1/10W R239 1-218-887-11 METAL CHIP 47K 0.5% 1/10W R240 1-218-839-11 METAL CHIP 470 0.5% 1/10W R241 1-218-845-11 METAL CHIP 820 0.5% 1/10W R242 1-218-847-11 METAL CHIP 1K 0.5% 1/10W R243 1-218-845-11 METAL CHIP 820 0.5% 1/10W R244 1-218-847-11 METAL CHIP 1K 0.5% 1/10W R245 1-218-855-11 METAL CHIP 2.2K 0.5% 1/10W R246 1-218-845-11 METAL CHIP 820 0.5% 1/10W R247 1-218-845-11 METAL CHIP 820 0.5% 1/10W R248 1-218-855-11 METAL CHIP 2.2K 0.5% 1/10W R249 1-218-887-11 METAL CHIP 47K 0.5% 1/10W R250 1-218-839-11 METAL CHIP 470 0.5% 1/10W R251 1-218-845-11 METAL CHIP 820 0.5% 1/10W R252 1-218-847-11 METAL CHIP 1K 0.5% 1/10W R253 1-218-845-11 METAL CHIP 820 0.5% 1/10W R254 1-218-847-11 METAL CHIP 1K 0.5% 1/10W R255 1-218-855-11 METAL CHIP 2.2K 0.5% 1/10W R256 1-218-845-11 METAL CHIP 820 0.5% 1/10W R257 1-218-845-11 METAL CHIP 820 0.5% 1/10W R258 1-218-855-11 METAL CHIP 2.2K 0.5% 1/10W R259 1-218-887-11 METAL CHIP 47K 0.5% 1/10W R260 1-218-839-11 METAL CHIP 470 0.5% 1/10W R261 1-218-845-11 METAL CHIP 820 0.5% 1/10W R262 1-218-847-11 METAL CHIP 1K 0.5% 1/10W R263 1-218-845-11 METAL CHIP 820 0.5% 1/10W R264 1-218-847-11 METAL CHIP 1K 0.5% 1/10W R265 1-218-855-11 METAL CHIP 2.2K 0.5% 1/10W R266 1-218-845-11 METAL CHIP 820 0.5% 1/10W R267 1-218-845-11 METAL CHIP 820 0.5% 1/10W R268 1-218-855-11 METAL CHIP 2.2K 0.5% 1/10W R269 1-218-887-11 METAL CHIP 47K 0.5% 1/10W R270 1-218-839-11 METAL CHIP 470 0.5% 1/10W R271 1-218-847-11 METAL CHIP 1K 0.5% 1/10W R272 1-218-847-11 METAL CHIP 1K 0.5% 1/10W R273 1-218-855-11 METAL CHIP 2.2K 0.5% 1/10W R274 1-218-845-11 METAL CHIP 820 0.5% 1/10W R275 1-218-845-11 METAL CHIP 820 0.5% 1/10W AV www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 105 DVP-CX995V R276 1-218-855-11 METAL CHIP 2.2K 0.5% 1/10W R277 1-218-887-11 METAL CHIP 47K 0.5% 1/10W R278 1-218-839-11 METAL CHIP 470 0.5% 1/10W R279 1-218-845-11 METAL CHIP 820 0.5% 1/10W R280 1-218-845-11 METAL CHIP 820 0.5% 1/10W R281 1-218-823-11 METAL CHIP 100 0.5% 1/10W R282 1-218-823-11 METAL CHIP 100 0.5% 1/10W R283 1-218-823-11 METAL CHIP 100 0.5% 1/10W R284 1-218-823-11 METAL CHIP 100 0.5% 1/10W R285 1-218-823-11 METAL CHIP 100 0.5% 1/10W R286 1-218-823-11 METAL CHIP 100 0.5% 1/10W R287 1-218-823-11 METAL CHIP 100 0.5% 1/10W R288 1-218-823-11 METAL CHIP 100 0.5% 1/10W R289 1-218-823-11 METAL CHIP 100 0.5% 1/10W R290 1-218-823-11 METAL CHIP 100 0.5% 1/10W R301 1-216-827-11 METAL CHIP 3.3K 5% 1/10W R302 1-216-827-11 METAL CHIP 3.3K 5% 1/10W R303 1-216-827-11 METAL CHIP 3.3K 5% 1/10W R304 1-216-827-11 METAL CHIP 3.3K 5% 1/10W R305 1-216-827-11 METAL CHIP 3.3K 5% 1/10W R306 1-216-827-11 METAL CHIP 3.3K 5% 1/10W R307 1-216-827-11 METAL CHIP 3.3K 5% 1/10W R308 1-216-827-11 METAL CHIP 3.3K 5% 1/10W R311 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R312 1-216-833-11 METAL CHIP 10K 5% 1/10W R313 1-216-841-11 METAL CHIP 47K 5% 1/10W R314 1-216-833-11 METAL CHIP 10K 5% 1/10W R315 1-216-833-11 METAL CHIP 10K 5% 1/10W R316 1-216-845-11 METAL CHIP 100K 5% 1/10W R321 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R322 1-216-833-11 METAL CHIP 10K 5% 1/10W R323 1-216-841-11 METAL CHIP 47K 5% 1/10W R324 1-216-833-11 METAL CHIP 10K 5% 1/10W R325 1-216-833-11 METAL CHIP 10K 5% 1/10W R326 1-216-845-11 METAL CHIP 100K 5% 1/10W R331 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R332 1-216-833-11 METAL CHIP 10K 5% 1/10W R333 1-216-841-11 METAL CHIP 47K 5% 1/10W R334 1-216-833-11 METAL CHIP 10K 5% 1/10W R335 1-216-833-11 METAL CHIP 10K 5% 1/10W R336 1-216-845-11 METAL CHIP 100K 5% 1/10W R341 1-216-821-11 METAL CHIP 1K 5% 1/10W R342 1-216-821-11 METAL CHIP 1K 5% 1/10W R343 1-216-821-11 METAL CHIP 1K 5% 1/10W R344 1-216-813-11 METAL CHIP 220 5% 1/10W R345 1-216-807-11 METAL CHIP 68 5% 1/10W R346 1-216-833-11 METAL CHIP 10K 5% 1/10W R351 1-216-833-11 METAL CHIP 10K 5% 1/10W R352 1-216-817-11 METAL CHIP 470 5% 1/10W R354 1-216-845-11 METAL CHIP 100K 5% 1/10W R355 1-216-845-11 METAL CHIP 100K 5% 1/10W R356 1-216-830-11 METAL CHIP 5.6K 5% 1/10W R357 1-216-833-11 METAL CHIP 10K 5% 1/10W R358 1-216-864-11 SHORT CHIP 0 R359 1-216-864-11 SHORT CHIP 0 R362 1-216-864-11 SHORT CHIP 0 R373 1-216-864-11 SHORT CHIP 0 R374 1-216-833-11 METAL CHIP 10K 5% 1/10W R375 1-208-794-11 METAL CHIP 3.3K 0.5% 1/10W R376 1-208-794-11 METAL CHIP 3.3K 0.5% 1/10W R377 1-208-794-11 METAL CHIP 3.3K 0.5% 1/10W R378 1-216-833-11 METAL CHIP 10K 5% 1/10W R379 1-216-821-11 METAL CHIP 1K 5% 1/10W R380 1-216-839-11 METAL CHIP 33K 5% 1/10W R382 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R383 1-216-841-11 METAL CHIP 47K 5% 1/10W R403 1-216-809-11 METAL CHIP 100 5% 1/10W R405 1-216-864-11 SHORT CHIP 0 R406 1-216-864-11 SHORT CHIP 0 R407 1-216-864-11 SHORT CHIP 0 R408 1-216-864-11 SHORT CHIP 0 R409 1-216-864-11 SHORT CHIP 0 R410 1-216-809-11 METAL CHIP 100 5% 1/10W R411 1-216-864-11 SHORT CHIP 0 R412 1-216-815-11 METAL CHIP 330 5% 1/10W R413 1-216-815-11 METAL CHIP 330 5% 1/10W R414 1-216-815-11 METAL CHIP 330 5% 1/10W R415 1-216-815-11 METAL CHIP 330 5% 1/10W R416 1-216-815-11 METAL CHIP 330 5% 1/10W R417 1-216-815-11 METAL CHIP 330 5% 1/10W R418 1-216-815-11 METAL CHIP 330 5% 1/10W R419 1-216-815-11 METAL CHIP 330 5% 1/10W R421 1-216-815-11 METAL CHIP 330 5% 1/10W R422 1-216-815-11 METAL CHIP 330 5% 1/10W R440 1-216-809-11 METAL CHIP 100 5% 1/10W R451 1-216-864-11 SHORT CHIP 0 R455 1-216-864-11 SHORT CHIP 0 R459 1-216-864-11 SHORT CHIP 0 R463 1-216-809-11 METAL CHIP 100 5% 1/10W R476 1-216-805-11 METAL CHIP 47 5% 1/10W R477 1-216-805-11 METAL CHIP 47 5% 1/10W R478 1-216-805-11 METAL CHIP 47 5% 1/10W R479 1-216-805-11 METAL CHIP 47 5% 1/10W R480 1-218-859-11 METAL CHIP 3.3K 0.5% 1/10W R481 1-218-845-11 METAL CHIP 820 0.5% 1/10W R502 1-216-864-11 SHORT CHIP 0 R509 1-216-864-11 SHORT CHIP 0 R511 1-216-864-11 SHORT CHIP 0 R512 1-216-864-11 SHORT CHIP 0 R519 1-216-819-11 METAL CHIP 680 5% 1/10W R520 1-216-833-11 METAL CHIP 10K 5% 1/10W R521 1-216-821-11 METAL CHIP 1K 5% 1/10W R522 1-216-821-11 METAL CHIP 1K 5% 1/10W R523 1-216-809-11 METAL CHIP 100 5% 1/10W R524 1-218-834-11 METAL CHIP 300 0.5% 1/10W R525 1-218-834-11 METAL CHIP 300 0.5% 1/10W R526 1-218-834-11 METAL CHIP 300 0.5% 1/10W R527 1-218-834-11 METAL CHIP 300 0.5% 1/10W R528 1-218-834-11 METAL CHIP 300 0.5% 1/10W R529 1-218-834-11 METAL CHIP 300 0.5% 1/10W R530 1-216-864-11 SHORT CHIP 0 R531 1-216-864-11 SHORT CHIP 0 R532 1-216-864-11 SHORT CHIP 0 R533 1-216-864-11 SHORT CHIP 0 R534 1-216-864-11 SHORT CHIP 0 AV www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 106 DVP-CX995V R535 1-216-864-11 SHORT CHIP 0 R537 1-216-864-11 SHORT CHIP 0 R600 1-216-809-11 METAL CHIP 100 5% 1/10W R601 1-216-809-11 METAL CHIP 100 5% 1/10W R602 1-216-809-11 METAL CHIP 100 5% 1/10W R604 1-216-864-11 SHORT CHIP 0 R606 1-216-864-11 SHORT CHIP 0 R607 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R609 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R611 1-216-864-11 SHORT CHIP 0 R612 1-218-839-11 METAL CHIP 470 0.5% 1/10W R613 1-211-736-11 METAL CHIP 5.1 5% 1/10W R614 1-216-833-11 METAL CHIP 10K 5% 1/10W R615 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R616 1-216-841-11 METAL CHIP 47K 5% 1/10W R617 1-216-864-11 SHORT CHIP 0 R618 1-216-864-11 SHORT CHIP 0 R619 1-216-864-11 SHORT CHIP 0 R629 1-216-864-11 SHORT CHIP 0 R632 1-216-864-11 SHORT CHIP 0 R667 1-218-853-11 METAL CHIP 1.8K 0.5% 1/10W R668 1-218-853-11 METAL CHIP 1.8K 0.5% 1/10W R1016 1-216-833-11 METAL CHIP 10K 5% 1/10W < COMPOSITION CIRCUIT BLOCK > RB401 1-234-370-21 RES, NETWORK 22 (1005X4) RB402 1-234-370-21 RES, NETWORK 22 (1005X4) RB403 1-234-370-21 RES, NETWORK 22 (1005X4) RB404 1-234-370-21 RES, NETWORK 22 (1005X4) RB405 1-234-370-21 RES, NETWORK 22 (1005X4) RB406 1-234-370-21 RES, NETWORK 22 (1005X4) RB407 1-234-370-21 RES, NETWORK 22 (1005X4) RB408 1-234-371-21 RES, NETWORK 47 (1005X4) RB409 1-234-371-21 RES, NETWORK 47 (1005X4) RB410 1-234-371-21 RES, NETWORK 47 (1005X4) RB411 1-234-371-21 RES, NETWORK 47 (1005X4) RB412 1-234-371-21 RES, NETWORK 47 (1005X4) RB413 1-234-371-21 RES, NETWORK 47 (1005X4) RB414 1-234-371-21 RES, NETWORK 47 (1005X4) RB415 1-234-400-21 CONDUCTOR, NETWORK (2010X4) RB416 1-234-400-21 CONDUCTOR, NETWORK (2010X4) RB419 1-234-371-21 RES, NETWORK 47 (1005X4) RB420 1-234-371-21 RES, NETWORK 47 (1005X4) RB421 1-234-371-21 RES, NETWORK 47 (1005X4) RB422 1-234-371-21 RES, NETWORK 47 (1005X4) RB423 1-234-371-21 RES, NETWORK 47 (1005X4) RB424 1-234-371-21 RES, NETWORK 47 (1005X4) RB425 1-234-371-21 RES, NETWORK 47 (1005X4) RB426 1-234-371-21 RES, NETWORK 47 (1005X4) RB427 1-234-371-21 RES, NETWORK 47 (1005X4) RB428 1-234-371-21 RES, NETWORK 47 (1005X4) RB429 1-234-387-21 RES, NETWORK 330 (1005X4) RB430 1-234-387-21 RES, NETWORK 330 (1005X4) RB601 1-239-662-81 RESISTOR, NETWORK 10 RB602 1-239-662-81 RESISTOR, NETWORK 10 RB603 1-239-662-81 RESISTOR, NETWORK 10 RB604 1-239-662-81 RESISTOR, NETWORK 10 < VARIABLE RESISTOR > RV500 1-241-761-11 RES, ADJ CERMET 1K RV501 1-241-761-11 RES, ADJ CERMET 1K ************************************************************ D. SENS IN BOARD **************** * 4-985-300-02 HOLDER (P-T) < PHOTO TRANSISTOR > Q81 8-729-921-53 PHOTO TRANSISTOR 83F1E000F ************************************************************ D. SENS OUT BOARD ***************** * 4-976-473-01 HOLDER (LED-S) < LED > D81 8-719-055-84 LED GL528VS1 (DISC DETECT) ************************************************************ DOOR MOTOR BOARD ****************** ************************************************************ DOOR SW BOARD *************** < SWITCH > S611 1-786-154-11 LEVER SLIDE SWITCH (DOOR OPEN/CLOSE) S612 1-786-154-11 LEVER SLIDE SWITCH (POP-UP) ************************************************************ A-1076-698-A DRIVER BOARD, COMPLETE *********************** < CAPACITOR > C901 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C902 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C903 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C904 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C905 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C906 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C907 1-109-953-11 ELECT 2.2uF 20% 50V C908 1-100-385-91 CERAMIC CHIP 0.47uF 25V C909 1-100-385-91 CERAMIC CHIP 0.47uF 25V C910 1-100-385-91 CERAMIC CHIP 0.47uF 25V C911 1-131-992-11 CERAMIC CHIP 100000PF 35V C913 1-131-992-11 CERAMIC CHIP 100000PF 35V C914 1-126-947-11 ELECT 47uF 20% 35V C915 1-126-947-11 ELECT 47uF 20% 35V < CONNECTOR > * CN901 1-568-937-11 PIN, CONNECTOR 10P CN903 1-506-469-11 PIN, CONNECTOR 4P * CN904 1-568-934-11 PIN, CONNECTOR 7P * CN905 1-506-469-11 PIN, CONNECTOR 4P AV D. SENS IN D. SENS OUT DOOR MOTOR DOOR SW DRIVER www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 107 DVP-CX995V * CN906 1-564-705-11 PIN, CONNECTOR (SMALL TYPE) 3P < DIODE > D935 8-719-025-49 DIODE 02CZ15-TE85L < EARTH TERMINAL > * G901 1-537-738-21 TERMINAL, EARTH < IC > IC941 8-759-822-38 IC LA6510 IC961 8-759-822-38 IC LA6510 < TRANSISTOR > Q931 8-729-230-49 TRANSISTOR 2SC2712-YG Q941 8-729-424-18 TRANSISTOR UN2113 Q942 8-729-421-19 TRANSISTOR UN2213 Q951 8-729-424-18 TRANSISTOR UN2113 Q952 8-729-421-19 TRANSISTOR UN2213 < RESISTOR > R901 1-216-797-11 METAL CHIP 10 5% 1/10W R902 1-240-915-11 RES-CHIP 1 1% 1/2W R903 1-240-915-11 RES-CHIP 1 1% 1/2W R904 1-216-797-11 METAL CHIP 10 5% 1/10W R905 1-240-915-11 RES-CHIP 1 1% 1/2W R906 1-216-835-11 METAL CHIP 15K 5% 1/10W R907 1-240-915-11 RES-CHIP 1 1% 1/2W R908 1-216-835-11 METAL CHIP 15K 5% 1/10W R909 1-216-848-11 METAL CHIP 180K 5% 1/10W R910 1-218-291-11 METAL CHIP 16K 5% 1/10W R911 1-216-847-11 METAL CHIP 150K 5% 1/10W R912 1-216-847-11 METAL CHIP 150K 5% 1/10W R913 1-216-848-11 METAL CHIP 180K 5% 1/10W R914 1-216-848-11 METAL CHIP 180K 5% 1/10W R915 1-218-291-11 METAL CHIP 16K 5% 1/10W R916 1-216-849-11 METAL CHIP 220K 5% 1/10W R917 1-216-845-11 METAL CHIP 100K 5% 1/10W R918 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R919 1-240-915-11 RES-CHIP 1 1% 1/2W R920 1-240-915-11 RES-CHIP 1 1% 1/2W R921 1-216-847-11 METAL CHIP 150K 5% 1/10W R922 1-216-845-11 METAL CHIP 100K 5% 1/10W R923 1-216-821-11 METAL CHIP 1K 5% 1/10W R924 1-216-809-11 METAL CHIP 100 5% 1/10W R925 1-216-821-11 METAL CHIP 1K 5% 1/10W R926 1-216-845-11 METAL CHIP 100K 5% 1/10W R927 1-216-847-11 METAL CHIP 150K 5% 1/10W R928 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R929 1-240-915-11 RES-CHIP 1 1% 1/2W R930 1-240-915-11 RES-CHIP 1 1% 1/2W R931 1-216-845-11 METAL CHIP 100K 5% 1/10W R932 1-216-825-11 METAL CHIP 2.2K 5% 1/10W R933 1-216-809-11 METAL CHIP 100 5% 1/10W R934 1-216-825-11 METAL CHIP 2.2K 5% 1/10W R935 1-216-809-11 METAL CHIP 100 5% 1/10W R936 1-216-825-11 METAL CHIP 2.2K 5% 1/10W R937 1-216-825-11 METAL CHIP 2.2K 5% 1/10W R941 1-216-821-11 METAL CHIP 1K 5% 1/10W R942 1-216-825-11 METAL CHIP 2.2K 5% 1/10W R943 1-216-825-11 METAL CHIP 2.2K 5% 1/10W R944 1-216-833-11 METAL CHIP 10K 5% 1/10W R945 1-216-837-11 METAL CHIP 22K 5% 1/10W ************************************************************ KEY BOARD BOARD **************** < CAPACITOR > C821 1-164-156-11 CERAMIC CHIP 0.1uF 25V C822 1-164-156-11 CERAMIC CHIP 0.1uF 25V C823 1-126-935-11 ELECT 470uF 20% 16V < CONNECTOR > * CNP503 1-568-942-11 PIN, CONNECTOR 4P J821 1-785-945-11 CONNECTOR, DIN (KEYBOARD) < FILTER > L821 1-424-122-11 FILTER, NOISE L822 1-424-122-11 FILTER, NOISE L823 1-424-122-11 FILTER, NOISE L824 1-424-122-11 FILTER, NOISE ************************************************************ LED BOARD ********** < CAPACITOR > C801 1-164-156-11 CERAMIC CHIP 0.1uF 25V < CONNECTOR > CNP504 1-785-328-11 PIN, CONNECTOR (LIGHT ANGRE) 2P < LED > D801 6-500-329-01 LED SELU5E23C-PTP15 (TABLE ILLUMINATION) < RESISTOR > R801 1-216-805-11 METAL CHIP 47 5% 1/10W ************************************************************ LOADING MOTOR BOARD ********************* ************************************************************ LOADING SW BOARD ***************** < SWITCH > S621 1-786-154-11 LEVER SLIDE SWITCH (LOADING DETECT) ************************************************************ DRIVER KEY BOARD LED LOADING MOTOR LOADING SW www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 108 DVP-CX995V LOCK SW BOARD ************** < SWITCH > S622 1-771-604-11 SWITCH, DETECTION (LOCK) ************************************************************ A-1132-163-A MB BOARD, COMPLETE ******************* < CAPACITOR > C102 1-126-206-11 ELECT CHIP 100uF 20% 6.3V C103 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C104 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C105 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C106 1-162-919-11 CERAMIC CHIP 22PF 5% 50V C107 1-162-919-11 CERAMIC CHIP 22PF 5% 50V C108 1-162-919-11 CERAMIC CHIP 22PF 5% 50V C109 1-162-919-11 CERAMIC CHIP 22PF 5% 50V C110 1-162-919-11 CERAMIC CHIP 22PF 5% 50V C111 1-162-919-11 CERAMIC CHIP 22PF 5% 50V C112 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C113 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C114 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C115 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C116 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V C117 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C118 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C119 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C120 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C121 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V C122 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C123 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C124 1-124-778-00 ELECT CHIP 22uF 20% 6.3V C125 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C126 1-126-206-11 ELECT CHIP 100uF 20% 6.3V C127 1-124-778-00 ELECT CHIP 22uF 20% 6.3V C128 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C129 1-124-778-00 ELECT CHIP 22uF 20% 6.3V C130 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C131 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C132 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C133 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C134 1-126-205-11 ELECT CHIP 47uF 20% 6.3V C135 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C136 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V C137 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C138 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C139 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C141 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C142 1-126-206-11 ELECT CHIP 100uF 20% 6.3V C144 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C145 1-124-778-00 ELECT CHIP 22uF 20% 6.3V C146 1-131-661-21 ELECT CHIP 100uF 20% 10V C147 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C149 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C150 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C151 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C153 1-162-927-11 CERAMIC CHIP 100PF 5% 50V C154 1-162-927-11 CERAMIC CHIP 100PF 5% 50V C155 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C156 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C158 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C159 1-124-778-00 ELECT CHIP 22uF 20% 6.3V C163 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C164 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C165 1-126-204-11 ELECT CHIP 47uF 20% 16V C166 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C167 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C170 1-162-918-11 CERAMIC CHIP 18PF 5% 50V C171 1-126-205-11 ELECT CHIP 47uF 20% 6.3V C172 1-162-912-11 CERAMIC CHIP 7PF 0.5PF 50V C173 1-126-205-11 ELECT CHIP 47uF 20% 6.3V C174 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C175 1-162-924-11 CERAMIC CHIP 56PF 5% 50V C176 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C177 1-164-315-11 CERAMIC CHIP 470PF 5% 50V C178 1-162-965-11 CERAMIC CHIP 0.0015uF 10% 50V C179 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C182 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C184 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C185 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C186 1-126-206-11 ELECT CHIP 100uF 20% 6.3V C187 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C188 1-126-206-11 ELECT CHIP 100uF 20% 6.3V C189 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V C190 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V C191 1-126-206-11 ELECT CHIP 100uF 20% 6.3V C194 1-124-778-00 ELECT CHIP 22uF 20% 6.3V C195 1-124-778-00 ELECT CHIP 22uF 20% 6.3V C196 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C201 1-162-909-11 CERAMIC CHIP 4PF 0.25PF 50V C202 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C203 1-162-909-11 CERAMIC CHIP 4PF 0.25PF 50V C204 1-126-208-21 ELECT CHIP 47uF 20% 4V C205 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C206 1-126-208-21 ELECT CHIP 47uF 20% 4V C207 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C208 1-124-778-00 ELECT CHIP 22uF 20% 6.3V C209 1-126-208-21 ELECT CHIP 47uF 20% 4V C210 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C211 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C212 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C213 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C214 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C215 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C216 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C217 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C218 1-126-208-21 ELECT CHIP 47uF 20% 4V C219 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C220 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C221 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C222 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C223 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C224 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C225 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V LOCK SW MB www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 109 DVP-CX995V C226 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C227 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C228 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C229 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C230 1-126-208-21 ELECT CHIP 47uF 20% 4V C231 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C232 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C233 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C234 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C235 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V C236 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C237 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V C238 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C239 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C240 1-162-927-11 CERAMIC CHIP 100PF 5% 50V C241 1-162-927-11 CERAMIC CHIP 100PF 5% 50V C242 1-124-778-00 ELECT CHIP 22uF 20% 6.3V C243 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C244 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C245 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C246 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C247 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C248 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C249 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C250 1-126-246-11 ELECT CHIP 220uF 20% 4V C251 1-126-206-11 ELECT CHIP 100uF 20% 6.3V C252 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C253 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C254 1-164-315-11 CERAMIC CHIP 470PF 5% 50V C255 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C257 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C258 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C259 1-126-208-21 ELECT CHIP 47uF 20% 4V C262 1-126-206-11 ELECT CHIP 100uF 20% 6.3V C263 1-126-246-11 ELECT CHIP 220uF 20% 4V C264 1-126-206-11 ELECT CHIP 100uF 20% 6.3V C265 1-126-204-11 ELECT CHIP 47uF 20% 16V C266 1-126-208-21 ELECT CHIP 47uF 20% 4V C301 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C305 1-162-927-11 CERAMIC CHIP 100PF 5% 50V C307 1-115-156-11 CERAMIC CHIP 1uF 10V C309 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C310 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C311 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V C313 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C314 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C315 1-126-208-21 ELECT CHIP 47uF 20% 4V C316 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C317 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C319 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C320 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C321 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C322 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C323 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C324 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C325 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C326 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C327 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C328 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C402 1-126-208-21 ELECT CHIP 47uF 20% 4V C403 1-126-208-21 ELECT CHIP 47uF 20% 4V C404 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C405 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C409 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C410 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C411 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C412 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C413 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C414 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C415 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C416 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C417 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C418 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C419 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C420 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C421 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C422 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C423 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C424 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C425 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C426 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C428 1-126-208-21 ELECT CHIP 47uF 20% 4V C429 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C501 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C502 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C503 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C505 1-126-206-11 ELECT CHIP 100uF 20% 6.3V C507 1-126-206-11 ELECT CHIP 100uF 20% 6.3V < CONNECTOR > CN101 1-784-879-21 CONNECTOR, FFC (LIF (NON-ZIF)) 31P CN102 1-573-768-21 PIN, CONNECTOR 5P CN203 1-816-296-21 PIN, CONNECTOR (PC BOARD) 9P CN205 1-784-881-21 CONNECTOR, FFC (LIF (NON-ZIF)) 33P CN301 1-691-550-21 PIN, CONNECTOR 3P CN303 1-784-875-21 CONNECTOR, FFC (LIF (NON-ZIF)) 25P CN304 1-760-388-21 PIN, CONNECTOR 9P CN305 1-695-223-21 PIN, CONNECTOR 10P CN307 1-580-057-21 PIN, CONNECTOR 4P CN501 1-784-836-21 CONNECTOR, FFC (LIF (NON-ZIF)) 29P < DIODE > D101 8-719-049-09 DIODE 1SS367-T3SONY D102 8-719-988-61 DIODE 1SS355TE-17 D202 8-719-049-09 DIODE 1SS367-T3SONY D301 8-719-988-61 DIODE 1SS355TE-17 D501 8-719-914-44 DIODE DAP202K D502 8-719-914-44 DIODE DAP202K D503 8-719-914-44 DIODE DAP202K < FERRITE BEAD/JUMPER RESISTOR > FB201 1-469-324-21 FERRITE, EMI (SMD) (2012) FB202 1-469-324-21 FERRITE, EMI (SMD) (2012) FB203 1-469-324-21 FERRITE, EMI (SMD) (2012) FB204 1-469-324-21 FERRITE, EMI (SMD) (2012) MB www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 110 DVP-CX995V FB205 1-469-324-21 FERRITE, EMI (SMD) (2012) FB206 1-469-324-21 FERRITE, EMI (SMD) (2012) FB207 1-469-324-21 FERRITE, EMI (SMD) (2012) FB208 1-469-324-21 FERRITE, EMI (SMD) (2012) FB209 1-469-324-21 FERRITE, EMI (SMD) (2012) FB210 1-469-324-21 FERRITE, EMI (SMD) (2012) FB211 1-216-864-11 SHORT CHIP 0 FB212 1-216-864-11 SHORT CHIP 0 FB213 1-216-864-11 SHORT CHIP 0 FB214 1-216-864-11 SHORT CHIP 0 FB215 1-216-864-11 SHORT CHIP 0 FB216 1-216-864-11 SHORT CHIP 0 FB217 1-216-864-11 SHORT CHIP 0 FB219 1-216-864-11 SHORT CHIP 0 FB220 1-216-864-11 SHORT CHIP 0 FB221 1-216-864-11 SHORT CHIP 0 < FILTER > FL201 1-234-177-21 FILTER, CHIP EMI FL202 1-234-177-21 FILTER, CHIP EMI FL203 1-234-177-21 FILTER, CHIP EMI FL204 1-234-177-21 FILTER, CHIP EMI FL205 1-234-177-21 FILTER, CHIP EMI FL206 1-234-177-21 FILTER, CHIP EMI FL207 1-234-177-21 FILTER, CHIP EMI FL208 1-233-893-21 FILTER, CHIP EMI FL209 1-234-177-21 FILTER, CHIP EMI FL401 1-234-177-21 FILTER, CHIP EMI FL402 1-234-177-21 FILTER, CHIP EMI < IC > * IC101 6-704-542-01 IC LMV324MTX/NOPB IC102 6-702-157-01 IC FAN8035L IC103 8-759-460-76 IC BA07FP-E2 IC104 6-708-022-01 IC STE6317ATXXY IC201 8-759-660-27 IC SN74HCU04APWR IC202 (Not supplied) IC M29W320ET70N6E-M005 IC203 6-708-493-01 IC HY57V281620ETP-HDR IC204 6-805-368-01 IC M29W320ET70N6E IC205 6-708-023-01 IC STE5588CVB IC206 8-759-548-99 IC SN74LV08APWR IC207 6-700-398-01 IC uPC2918T-E1 IC208 8-759-583-47 IC uPC2933T-E2 IC209 8-759-549-20 IC SN74LV541APWR IC302 8-759-350-42 IC PST9127NL IC304 6-805-432-01 IC uPD703260-YGF-S30-JBT-A IC305 8-759-350-42 IC PST9127NL IC306 6-704-158-01 IC S-80827CNUA-B8MT2G IC401 6-708-020-01 IC SAA7893HL IC403 6-708-494-01 IC HY57V641620ETP-HDR IC501 6-704-222-01 IC AK4358VQ-L < COIL > L101 1-414-398-11 INDUCTOR 10uH L102 1-410-389-31 INDUCTOR 47uH L103 1-410-389-31 INDUCTOR 47uH L104 1-414-398-11 INDUCTOR 10uH L105 1-414-394-41 INDUCTOR 2.2uH L106 1-414-392-41 INDUCTOR 1uH L108 1-414-392-41 INDUCTOR 1uH L201 1-414-392-41 INDUCTOR 1uH L202 1-414-392-41 INDUCTOR 1uH L203 1-414-398-11 INDUCTOR 10uH L401 1-414-398-11 INDUCTOR 10uH < TRANSISTOR > Q101 8-729-903-46 TRANSISTOR 2SB1132-P Q102 6-550-545-01 TRANSISTOR 2SC4617FTLQ Q103 8-729-903-46 TRANSISTOR 2SB1132-P Q104 6-550-545-01 TRANSISTOR 2SC4617FTLQ Q105 8-729-034-50 TRANSISTOR KTA1504 Q301 8-729-230-49 TRANSISTOR 2SC2712-YG Q302 8-729-230-49 TRANSISTOR 2SC2712-YG Q303 8-729-027-43 TRANSISTOR DTC114EKA-T146 Q304 8-729-027-28 TRANSISTOR DTA123EKA-T146 Q305 8-729-027-38 TRANSISTOR DTA144EKA-T146 Q306 8-729-027-38 TRANSISTOR DTA144EKA-T146 Q307 8-729-027-43 TRANSISTOR DTC114EKA-T146 < RESISTOR/CAPACITOR/FERRITE BEAD > R101 1-216-809-11 METAL CHIP 100 5% 1/10W R102 1-216-809-11 METAL CHIP 100 5% 1/10W R103 1-216-809-11 METAL CHIP 100 5% 1/10W R104 1-216-809-11 METAL CHIP 100 5% 1/10W R105 1-216-809-11 METAL CHIP 100 5% 1/10W R106 1-216-809-11 METAL CHIP 100 5% 1/10W R107 1-216-809-11 METAL CHIP 100 5% 1/10W R108 1-218-871-11 METAL CHIP 10K 0.5% 1/10W R109 1-218-871-11 METAL CHIP 10K 0.5% 1/10W R110 1-216-801-11 METAL CHIP 22 5% 1/10W R111 1-216-833-11 METAL CHIP 10K 5% 1/10W R112 1-216-833-11 METAL CHIP 10K 5% 1/10W R113 1-216-833-11 METAL CHIP 10K 5% 1/10W R114 1-216-833-11 METAL CHIP 10K 5% 1/10W R115 1-216-833-11 METAL CHIP 10K 5% 1/10W R116 1-216-833-11 METAL CHIP 10K 5% 1/10W R117 1-216-801-11 METAL CHIP 22 5% 1/10W R118 1-216-833-11 METAL CHIP 10K 5% 1/10W R119 1-218-840-11 METAL CHIP 510 0.5% 1/10W R120 1-218-840-11 METAL CHIP 510 0.5% 1/10W R121 1-218-840-11 METAL CHIP 510 0.5% 1/10W R122 1-218-840-11 METAL CHIP 510 0.5% 1/10W R123 1-218-840-11 METAL CHIP 510 0.5% 1/10W R124 1-219-724-11 METAL CHIP 1 1% 1/4W R125 1-218-878-11 METAL CHIP 20K 0.5% 1/10W R126 1-216-814-11 METAL CHIP 270 5% 1/10W R127 1-216-813-11 METAL CHIP 220 5% 1/10W R128 1-218-882-11 METAL CHIP 30K 0.5% 1/10W R129 1-216-821-11 METAL CHIP 1K 5% 1/10W R130 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W R131 1-216-841-11 METAL CHIP 47K 5% 1/10W R132 1-216-833-11 METAL CHIP 10K 5% 1/10W R133 1-216-841-11 METAL CHIP 47K 5% 1/10W R134 1-216-833-11 METAL CHIP 10K 5% 1/10W R135 1-218-863-11 METAL CHIP 4.7K 0.5% 1/10W MB www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 111 DVP-CX995V R136 1-218-863-11 METAL CHIP 4.7K 0.5% 1/10W R137 1-216-833-11 METAL CHIP 10K 5% 1/10W R138 1-216-833-11 METAL CHIP 10K 5% 1/10W R139 1-216-801-11 METAL CHIP 22 5% 1/10W R140 1-218-863-11 METAL CHIP 4.7K 0.5% 1/10W R141 1-216-833-11 METAL CHIP 10K 5% 1/10W R142 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W R143 1-216-833-11 METAL CHIP 10K 5% 1/10W R144 1-218-863-11 METAL CHIP 4.7K 0.5% 1/10W R145 1-216-801-11 METAL CHIP 22 5% 1/10W R146 1-216-864-11 SHORT CHIP 0 R147 1-218-881-11 METAL CHIP 27K 0.5% 1/10W R148 1-218-880-11 METAL CHIP 24K 0.5% 1/10W R149 1-216-805-11 METAL CHIP 47 5% 1/10W R150 1-216-814-11 METAL CHIP 270 5% 1/10W R151 1-216-813-11 METAL CHIP 220 5% 1/10W R152 1-216-805-11 METAL CHIP 47 5% 1/10W R153 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W R154 1-216-805-11 METAL CHIP 47 5% 1/10W R155 1-218-879-11 METAL CHIP 22K 0.5% 1/10W R156 1-218-879-11 METAL CHIP 22K 0.5% 1/10W R157 1-216-805-11 METAL CHIP 47 5% 1/10W R158 1-216-805-11 METAL CHIP 47 5% 1/10W R159 1-216-805-11 METAL CHIP 47 5% 1/10W R160 1-218-879-11 METAL CHIP 22K 0.5% 1/10W R161 1-218-875-11 METAL CHIP 15K 0.5% 1/10W R162 1-218-889-11 METAL CHIP 56K 0.5% 1/10W R163 1-218-889-11 METAL CHIP 56K 0.5% 1/10W R164 1-216-805-11 METAL CHIP 47 5% 1/10W R165 1-218-871-11 METAL CHIP 10K 0.5% 1/10W R166 1-218-871-11 METAL CHIP 10K 0.5% 1/10W R167 1-218-883-11 METAL CHIP 33K 0.5% 1/10W R168 1-218-883-11 METAL CHIP 33K 0.5% 1/10W R169 1-216-864-11 SHORT CHIP 0 R170 1-216-864-11 SHORT CHIP 0 R171 1-216-845-11 METAL CHIP 100K 5% 1/10W R172 1-216-845-11 METAL CHIP 100K 5% 1/10W R173 1-216-789-11 METAL CHIP 2.2 5% 1/10W R174 1-216-821-11 METAL CHIP 1K 5% 1/10W R175 1-216-833-11 METAL CHIP 10K 5% 1/10W R176 1-216-833-11 METAL CHIP 10K 5% 1/10W R177 1-216-809-11 METAL CHIP 100 5% 1/10W R178 1-218-873-11 METAL CHIP 12K 0.5% 1/10W R179 1-218-843-11 METAL CHIP 680 0.5% 1/10W R180 1-219-724-11 METAL CHIP 1 1% 1/4W R181 1-216-833-11 METAL CHIP 10K 5% 1/10W R182 1-219-724-11 METAL CHIP 1 1% 1/4W R183 1-216-833-11 METAL CHIP 10K 5% 1/10W R184 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R185 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R186 1-216-833-11 METAL CHIP 10K 5% 1/10W R187 1-216-833-11 METAL CHIP 10K 5% 1/10W R188 1-216-837-11 METAL CHIP 22K 5% 1/10W R189 1-216-837-11 METAL CHIP 22K 5% 1/10W R190 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R192 1-219-570-11 METAL CHIP 10M 5% 1/10W R193 1-219-724-11 METAL CHIP 1 1% 1/4W R194 1-216-864-11 SHORT CHIP 0 R196 1-216-833-11 METAL CHIP 10K 5% 1/10W R197 1-216-833-11 METAL CHIP 10K 5% 1/10W R201 1-216-857-11 METAL CHIP 1M 5% 1/10W R202 1-216-811-11 METAL CHIP 150 5% 1/10W R203 1-216-805-11 METAL CHIP 47 5% 1/10W R204 1-216-864-11 SHORT CHIP 0 R205 1-216-805-11 METAL CHIP 47 5% 1/10W R206 1-216-864-11 SHORT CHIP 0 R207 1-216-864-11 SHORT CHIP 0 R208 1-216-864-11 SHORT CHIP 0 R209 1-216-833-11 METAL CHIP 10K 5% 1/10W R210 1-216-864-11 SHORT CHIP 0 R211 1-216-833-11 METAL CHIP 10K 5% 1/10W R212 1-216-833-11 METAL CHIP 10K 5% 1/10W R213 1-216-864-11 SHORT CHIP 0 R214 1-216-833-11 METAL CHIP 10K 5% 1/10W R215 1-216-864-11 SHORT CHIP 0 R216 1-216-833-11 METAL CHIP 10K 5% 1/10W R217 1-216-833-11 METAL CHIP 10K 5% 1/10W R218 1-216-864-11 SHORT CHIP 0 R219 1-216-833-11 METAL CHIP 10K 5% 1/10W R220 1-216-864-11 SHORT CHIP 0 R221 1-216-833-11 METAL CHIP 10K 5% 1/10W R222 1-216-864-11 SHORT CHIP 0 R223 1-216-864-11 SHORT CHIP 0 R224 1-216-833-11 METAL CHIP 10K 5% 1/10W R225 1-216-805-11 METAL CHIP 47 5% 1/10W R226 1-216-805-11 METAL CHIP 47 5% 1/10W R227 1-216-833-11 METAL CHIP 10K 5% 1/10W R228 1-216-833-11 METAL CHIP 10K 5% 1/10W R229 1-216-805-11 METAL CHIP 47 5% 1/10W R230 1-216-805-11 METAL CHIP 47 5% 1/10W R231 1-216-864-11 SHORT CHIP 0 R232 1-216-797-11 METAL CHIP 10 5% 1/10W R233 1-216-805-11 METAL CHIP 47 5% 1/10W R234 1-216-833-11 METAL CHIP 10K 5% 1/10W R235 1-216-805-11 METAL CHIP 47 5% 1/10W R236 1-216-805-11 METAL CHIP 47 5% 1/10W R237 1-216-805-11 METAL CHIP 47 5% 1/10W R238 1-216-805-11 METAL CHIP 47 5% 1/10W R239 1-216-805-11 METAL CHIP 47 5% 1/10W R240 1-216-805-11 METAL CHIP 47 5% 1/10W R241 1-216-805-11 METAL CHIP 47 5% 1/10W R242 1-216-841-11 METAL CHIP 47K 5% 1/10W R243 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R244 1-216-805-11 METAL CHIP 47 5% 1/10W R245 1-216-805-11 METAL CHIP 47 5% 1/10W R246 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R247 1-216-805-11 METAL CHIP 47 5% 1/10W R248 1-216-805-11 METAL CHIP 47 5% 1/10W R249 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R250 1-216-805-11 METAL CHIP 47 5% 1/10W R251 1-216-805-11 METAL CHIP 47 5% 1/10W R252 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R253 1-216-805-11 METAL CHIP 47 5% 1/10W R254 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R255 1-216-805-11 METAL CHIP 47 5% 1/10W MB www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 112 DVP-CX995V R256 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R257 1-216-805-11 METAL CHIP 47 5% 1/10W R258 1-216-805-11 METAL CHIP 47 5% 1/10W R259 1-216-864-11 SHORT CHIP 0 R260 1-216-805-11 METAL CHIP 47 5% 1/10W R261 1-216-797-11 METAL CHIP 10 5% 1/10W R262 1-216-824-11 METAL CHIP 1.8K 5% 1/10W R263 1-216-824-11 METAL CHIP 1.8K 5% 1/10W R264 1-216-797-11 METAL CHIP 10 5% 1/10W R265 1-216-797-11 METAL CHIP 10 5% 1/10W R266 1-216-805-11 METAL CHIP 47 5% 1/10W R267 1-216-833-11 METAL CHIP 10K 5% 1/10W R268 1-216-805-11 METAL CHIP 47 5% 1/10W R269 1-216-805-11 METAL CHIP 47 5% 1/10W R270 1-218-285-11 METAL CHIP 75 5% 1/10W R271 1-218-285-11 METAL CHIP 75 5% 1/10W R272 1-216-805-11 METAL CHIP 47 5% 1/10W R273 1-216-805-11 METAL CHIP 47 5% 1/10W R274 1-216-805-11 METAL CHIP 47 5% 1/10W R275 1-216-805-11 METAL CHIP 47 5% 1/10W R276 1-216-805-11 METAL CHIP 47 5% 1/10W R277 1-218-871-11 METAL CHIP 10K 0.5% 1/10W R278 1-218-871-11 METAL CHIP 10K 0.5% 1/10W R279 1-216-805-11 METAL CHIP 47 5% 1/10W R280 1-216-805-11 METAL CHIP 47 5% 1/10W R281 1-216-805-11 METAL CHIP 47 5% 1/10W R285 1-216-826-11 METAL CHIP 2.7K 5% 1/10W R289 1-216-805-11 METAL CHIP 47 5% 1/10W R296 1-216-833-11 METAL CHIP 10K 5% 1/10W R297 1-216-826-11 METAL CHIP 2.7K 5% 1/10W R298 1-216-797-11 METAL CHIP 10 5% 1/10W R299 1-216-826-11 METAL CHIP 2.7K 5% 1/10W R300 1-216-797-11 METAL CHIP 10 5% 1/10W R301 1-216-833-11 METAL CHIP 10K 5% 1/10W R302 1-216-864-11 SHORT CHIP 0 R303 1-216-864-11 SHORT CHIP 0 R304 1-216-864-11 SHORT CHIP 0 R305 1-216-801-11 METAL CHIP 22 5% 1/10W R306 1-216-801-11 METAL CHIP 22 5% 1/10W R307 1-216-801-11 METAL CHIP 22 5% 1/10W R308 1-216-833-11 METAL CHIP 10K 5% 1/10W R309 1-216-801-11 METAL CHIP 22 5% 1/10W R310 1-216-809-11 METAL CHIP 100 5% 1/10W R311 1-216-801-11 METAL CHIP 22 5% 1/10W R312 1-216-809-11 METAL CHIP 100 5% 1/10W R313 1-216-801-11 METAL CHIP 22 5% 1/10W R314 1-216-833-11 METAL CHIP 10K 5% 1/10W R315 1-216-841-11 METAL CHIP 47K 5% 1/10W R316 1-216-841-11 METAL CHIP 47K 5% 1/10W R317 1-216-845-11 METAL CHIP 100K 5% 1/10W R318 1-216-833-11 METAL CHIP 10K 5% 1/10W R319 1-216-864-11 SHORT CHIP 0 R321 1-216-833-11 METAL CHIP 10K 5% 1/10W R322 1-216-864-11 SHORT CHIP 0 R325 1-216-809-11 METAL CHIP 100 5% 1/10W R326 1-216-809-11 METAL CHIP 100 5% 1/10W R327 1-216-845-11 METAL CHIP 100K 5% 1/10W R328 1-216-833-11 METAL CHIP 10K 5% 1/10W R330 1-216-833-11 METAL CHIP 10K 5% 1/10W R331 1-216-833-11 METAL CHIP 10K 5% 1/10W R332 1-216-833-11 METAL CHIP 10K 5% 1/10W R333 1-216-864-11 SHORT CHIP 0 R334 1-216-833-11 METAL CHIP 10K 5% 1/10W R337 1-216-833-11 METAL CHIP 10K 5% 1/10W R338 1-216-833-11 METAL CHIP 10K 5% 1/10W R341 1-216-853-11 METAL CHIP 470K 5% 1/10W R342 1-216-864-11 SHORT CHIP 0 R344 1-216-833-11 METAL CHIP 10K 5% 1/10W R345 1-216-833-11 METAL CHIP 10K 5% 1/10W R346 1-216-833-11 METAL CHIP 10K 5% 1/10W R347 1-216-833-11 METAL CHIP 10K 5% 1/10W R348 1-216-833-11 METAL CHIP 10K 5% 1/10W R349 1-216-864-11 SHORT CHIP 0 R350 1-216-833-11 METAL CHIP 10K 5% 1/10W R351 1-216-810-11 METAL CHIP 120 5% 1/10W R352 1-216-803-11 METAL CHIP 33 5% 1/10W R353 1-216-833-11 METAL CHIP 10K 5% 1/10W R354 1-216-833-11 METAL CHIP 10K 5% 1/10W R356 1-216-864-11 SHORT CHIP 0 R358 1-216-827-11 METAL CHIP 3.3K 5% 1/10W R360 1-216-833-11 METAL CHIP 10K 5% 1/10W R361 1-216-833-11 METAL CHIP 10K 5% 1/10W R362 1-216-833-11 METAL CHIP 10K 5% 1/10W R366 1-216-833-11 METAL CHIP 10K 5% 1/10W R368 1-216-864-11 SHORT CHIP 0 R369 1-216-864-11 SHORT CHIP 0 R370 1-216-833-11 METAL CHIP 10K 5% 1/10W R371 1-216-833-11 METAL CHIP 10K 5% 1/10W R372 1-216-864-11 SHORT CHIP 0 R381 1-216-809-11 METAL CHIP 100 5% 1/10W R407 1-216-809-11 METAL CHIP 100 5% 1/10W R414 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V R415 1-216-834-11 METAL CHIP 12K 5% 1/10W R417 1-216-833-11 METAL CHIP 10K 5% 1/10W R418 1-216-864-11 SHORT CHIP 0 R421 1-216-805-11 METAL CHIP 47 5% 1/10W R424 1-216-821-11 METAL CHIP 1K 5% 1/10W R425 1-216-833-11 METAL CHIP 10K 5% 1/10W R428 1-216-833-11 METAL CHIP 10K 5% 1/10W R429 1-216-864-11 SHORT CHIP 0 R501 1-216-864-11 SHORT CHIP 0 R505 1-216-797-11 METAL CHIP 10 5% 1/10W R506 1-216-864-11 SHORT CHIP 0 R508 1-216-864-11 SHORT CHIP 0 R510 1-216-864-11 SHORT CHIP 0 R613 1-216-864-11 SHORT CHIP 0 R615 1-216-864-11 SHORT CHIP 0 R616 1-216-864-11 SHORT CHIP 0 R617 1-216-864-11 SHORT CHIP 0 R618 1-216-864-11 SHORT CHIP 0 R619 1-216-864-11 SHORT CHIP 0 R641 1-216-864-11 SHORT CHIP 0 R642 1-216-864-11 SHORT CHIP 0 R1001 1-216-805-11 METAL CHIP 47 5% 1/10W R1002 1-216-833-11 METAL CHIP 10K 5% 1/10W MB www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 113 DVP-CX995V R1003 1-216-833-11 METAL CHIP 10K 5% 1/10W R1004 1-216-833-11 METAL CHIP 10K 5% 1/10W R1005 1-216-833-11 METAL CHIP 10K 5% 1/10W R1006 1-216-833-11 METAL CHIP 10K 5% 1/10W R1007 1-216-833-11 METAL CHIP 10K 5% 1/10W R1014 1-216-805-11 METAL CHIP 47 5% 1/10W R1015 1-216-805-11 METAL CHIP 47 5% 1/10W R1019 1-216-833-11 METAL CHIP 10K 5% 1/10W R1020 1-216-789-11 METAL CHIP 2.2 5% 1/10W R1022 1-216-864-11 SHORT CHIP 0 R1023 1-216-864-11 SHORT CHIP 0 R1024 1-216-801-11 METAL CHIP 22 5% 1/10W R1025 1-216-864-11 SHORT CHIP 0 R1027 1-216-805-11 METAL CHIP 47 5% 1/10W R1028 1-216-845-11 METAL CHIP 100K 5% 1/10W R1029 1-216-864-11 SHORT CHIP 0 R1033 1-216-864-11 SHORT CHIP 0 R1034 1-216-864-11 SHORT CHIP 0 R1035 1-216-833-11 METAL CHIP 10K 5% 1/10W R1036 1-216-833-11 METAL CHIP 10K 5% 1/10W R1038 1-216-833-11 METAL CHIP 10K 5% 1/10W R1039 1-216-864-11 SHORT CHIP 0 R1040 1-216-864-11 SHORT CHIP 0 R1041 1-216-864-11 SHORT CHIP 0 R1042 1-216-864-11 SHORT CHIP 0 R1043 1-216-833-11 METAL CHIP 10K 5% 1/10W R1047 1-400-330-21 INDUCTOR, FERRITE BEAD (1608) R1048 1-400-330-21 INDUCTOR, FERRITE BEAD (1608) R1049 1-400-330-21 INDUCTOR, FERRITE BEAD (1608) R1050 1-400-330-21 INDUCTOR, FERRITE BEAD (1608) R1051 1-400-330-21 INDUCTOR, FERRITE BEAD (1608) R1052 1-400-330-21 INDUCTOR, FERRITE BEAD (1608) R1053 1-400-330-21 INDUCTOR, FERRITE BEAD (1608) R1054 1-400-330-21 INDUCTOR, FERRITE BEAD (1608) R1055 1-500-283-11 INDUCTOR, FERRITE BEAD R1056 1-218-285-11 METAL CHIP 75 5% 1/10W R1057 1-216-809-11 METAL CHIP 100 5% 1/10W R1058 1-216-809-11 METAL CHIP 100 5% 1/10W R1059 1-216-805-11 METAL CHIP 47 5% 1/10W R1060 1-216-805-11 METAL CHIP 47 5% 1/10W R1061 1-216-809-11 METAL CHIP 100 5% 1/10W R1062 1-216-809-11 METAL CHIP 100 5% 1/10W R1063 1-216-809-11 METAL CHIP 100 5% 1/10W R1074 1-216-805-11 METAL CHIP 47 5% 1/10W < COMPOSITION CIRCUIT BLOCK > RB201 1-234-371-21 RES, NETWORK 47 (1005X4) RB202 1-234-371-21 RES, NETWORK 47 (1005X4) RB203 1-234-371-21 RES, NETWORK 47 (1005X4) RB204 1-242-962-21 RES, NETWORK 82X4 (1005) RB205 1-234-371-21 RES, NETWORK 47 (1005X4) RB206 1-234-371-21 RES, NETWORK 47 (1005X4) RB207 1-242-962-21 RES, NETWORK 82X4 (1005) RB208 1-234-371-21 RES, NETWORK 47 (1005X4) RB209 1-242-962-21 RES, NETWORK 82X4 (1005) RB210 1-234-371-21 RES, NETWORK 47 (1005X4) RB211 1-234-371-21 RES, NETWORK 47 (1005X4) RB212 1-234-371-21 RES, NETWORK 47 (1005X4) RB213 1-234-371-21 RES, NETWORK 47 (1005X4) RB214 1-242-962-21 RES, NETWORK 82X4 (1005) RB215 1-234-369-21 RES, NETWORK 10 (1005X4) RB216 1-234-369-21 RES, NETWORK 10 (1005X4) RB401 1-234-702-11 RES, NETWORK 68 (1005X4) RB402 1-234-702-11 RES, NETWORK 68 (1005X4) RB403 1-234-702-11 RES, NETWORK 68 (1005X4) RB404 1-234-702-11 RES, NETWORK 68 (1005X4) < VARIABLE RESISTOR > RV301 1-223-587-11 RES, ADJ, CARBON 22K < VIBRATOR > X201 1-795-630-11 VIBRATOR, CRYSTAL (27MHz) X301 1-795-121-21 VIBRATOR, CERAMIC (5MHz) ************************************************************ A-1076-700-A PANEL-L BOARD, COMPLETE ************************ 4-246-508-01 HOLDER (FL) 4-949-935-41 CUSHION (FL) < CAPACITOR > C1031 1-164-156-11 CERAMIC CHIP 0.1uF 25V C1032 1-164-156-11 CERAMIC CHIP 0.1uF 25V C1034 1-164-156-11 CERAMIC CHIP 0.1uF 25V C1035 1-164-156-11 CERAMIC CHIP 0.1uF 25V C1036 1-162-922-11 CERAMIC CHIP 39PF 5% 50V C1037 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V C1038 1-124-589-11 ELECT 47uF 20% 16V C1039 1-124-589-11 ELECT 47uF 20% 16V C1040 1-164-156-11 CERAMIC CHIP 0.1uF 25V C1042 1-164-156-11 CERAMIC CHIP 0.1uF 25V C1043 1-164-156-11 CERAMIC CHIP 0.1uF 25V C1044 1-164-156-11 CERAMIC CHIP 0.1uF 25V C1051 1-162-927-11 CERAMIC CHIP 100PF 5% 50V C1052 1-162-927-11 CERAMIC CHIP 100PF 5% 50V C1053 1-162-927-11 CERAMIC CHIP 100PF 5% 50V C1081 1-128-131-11 ELECT 22uF 20% 50V C1082 1-137-150-11 FILM 0.01uF 5% 100V C1083 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V C1085 1-128-131-11 ELECT 22uF 20% 50V C1086 1-128-131-11 ELECT 22uF 20% 50V C1087 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V C1088 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V C1089 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V < CONNECTOR > * CN1001 1-568-954-11 PIN, CONNECTOR 5P * CN1002 1-568-936-11 PIN, CONNECTOR 9P CN1003 1-779-293-11 CONNECTOR, FFC (LIF (NON-ZIF)) 25P < DIODE > D1001 6-500-647-01 LED SEL5E20C-STP15 (HDMI) D1002 6-500-647-01 LED SEL5E20C-STP15 (SA-CD) D1003 6-500-647-01 LED SEL5E20C-STP15 (MULTI CHANNEL) D1004 8-719-046-39 LED SEL5821A-TP15 (FL OFF) MB PANEL-L www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 114 DVP-CX995V D1081 8-719-041-97 DIODE MA113- (TX) D1082 8-719-041-97 DIODE MA113- (TX) D1083 8-719-041-97 DIODE MA113- (TX) D1084 8-719-041-97 DIODE MA113- (TX) D1085 8-719-083-71 DIODE UDZSTE-1730B D1086 8-719-069-56 DIODE UDZSTE-176.2B < JUMPER RESISTOR > FB1001 1-216-864-11 SHORT CHIP 0 < FLUORESCENT INDICATOR TUBE > FL1001 1-519-787-11 INDICATOR TUBE, FLUORESCENT < IC > IC1001 8-759-680-17 IC MSM9201-04GS-K IC1002 8-759-826-34 IC NJL74H400A < COIL > L1081 1-400-096-21 INDUCTOR 47uH L1082 1-400-096-21 INDUCTOR 47uH < TRANSISTOR > Q1001 8-729-027-43 TRANSISTOR DTC114EKA-T146 Q1002 8-729-027-43 TRANSISTOR DTC114EKA-T146 Q1003 8-729-027-43 TRANSISTOR DTC114EKA-T146 Q1004 8-729-027-43 TRANSISTOR DTC114EKA-T146 Q1006 8-729-027-43 TRANSISTOR DTC114EKA-T146 Q1007 8-729-027-43 TRANSISTOR DTC114EKA-T146 Q1008 8-729-027-43 TRANSISTOR DTC114EKA-T146 Q1009 8-729-027-43 TRANSISTOR DTC114EKA-T146 Q1010 8-729-120-28 TRANSISTOR 2SC1623-L5L6 Q1081 8-729-808-01 TRANSISTOR 2SD1622-S Q1082 8-729-808-01 TRANSISTOR 2SD1622-S Q1083 8-729-804-41 TRANSISTOR 2SB1122-S < RESISTOR > R1001 1-216-827-11 METAL CHIP 3.3K 5% 1/10W R1002 1-216-825-11 METAL CHIP 2.2K 5% 1/10W R1003 1-216-821-11 METAL CHIP 1K 5% 1/10W R1004 1-216-825-11 METAL CHIP 2.2K 5% 1/10W R1005 1-216-825-11 METAL CHIP 2.2K 5% 1/10W R1006 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R1007 1-216-833-11 METAL CHIP 10K 5% 1/10W R1008 1-216-837-11 METAL CHIP 22K 5% 1/10W R1011 1-216-805-11 METAL CHIP 47 5% 1/10W R1012 1-216-805-11 METAL CHIP 47 5% 1/10W R1013 1-216-805-11 METAL CHIP 47 5% 1/10W R1014 1-216-811-11 METAL CHIP 150 5% 1/10W R1021 1-216-864-11 SHORT CHIP 0 R1022 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R1023 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R1024 1-216-801-11 METAL CHIP 22 5% 1/10W R1025 1-216-801-11 METAL CHIP 22 5% 1/10W R1031 1-216-827-11 METAL CHIP 3.3K 5% 1/10W R1032 1-216-809-11 METAL CHIP 100 5% 1/10W R1033 1-216-809-11 METAL CHIP 100 5% 1/10W R1035 1-216-841-11 METAL CHIP 47K 5% 1/10W R1036 1-216-809-11 METAL CHIP 100 5% 1/10W R1040 1-216-864-11 SHORT CHIP 0 R1041 1-216-864-11 SHORT CHIP 0 R1042 1-216-864-11 SHORT CHIP 0 R1044 1-216-797-11 METAL CHIP 10 5% 1/10W R1051 1-216-797-11 METAL CHIP 10 5% 1/10W R1052 1-216-797-11 METAL CHIP 10 5% 1/10W R1053 1-216-797-11 METAL CHIP 10 5% 1/10W R1054 1-216-797-11 METAL CHIP 10 5% 1/10W R1055 1-216-797-11 METAL CHIP 10 5% 1/10W R1056 1-216-797-11 METAL CHIP 10 5% 1/10W R1057 1-216-809-11 METAL CHIP 100 5% 1/10W R1058 1-216-809-11 METAL CHIP 100 5% 1/10W R1059 1-216-809-11 METAL CHIP 100 5% 1/10W R1061 1-216-797-11 METAL CHIP 10 5% 1/10W R1062 1-216-797-11 METAL CHIP 10 5% 1/10W R1063 1-216-797-11 METAL CHIP 10 5% 1/10W R1064 1-216-797-11 METAL CHIP 10 5% 1/10W R1065 1-216-797-11 METAL CHIP 10 5% 1/10W R1066 1-216-797-11 METAL CHIP 10 5% 1/10W R1081 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W R1082 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W R1083 1-216-828-11 METAL CHIP 3.9K 5% 1/10W R1084 1-216-833-11 METAL CHIP 10K 5% 1/10W < SWITCH > S1001 1-771-410-21 SWITCH, TACTILE (FL OFF) S1002 1-771-410-21 SWITCH, TACTILE (TIME/TEXT) S1003 1-771-410-21 SWITCH, TACTILE (PICTURE MODE) S1004 1-771-410-21 SWITCH, TACTILE (REPEAT) S1006 1-771-410-21 SWITCH, TACTILE (FOLDER) S1007 1-771-410-21 SWITCH, TACTILE (ONE/ALL DISCS) S1008 1-771-410-21 SWITCH, TACTILE (I/1) S1009 1-771-410-21 SWITCH, TACTILE (LOAD) < TRANSFORMER > T1081 1-437-887-11 TRANSFORMER, DC-DC CONVERTER ************************************************************ A-1076-688-A PANEL-R BOARD, COMPLETE ************************ < CAPACITOR > C1199 1-164-156-11 CERAMIC CHIP 0.1uF 25V < DIODE > D1101 8-719-046-39 LED SEL5821A-TP15 (DISC CHANGE) D1102 8-719-046-41 LED SEL5521C-TP15 (DIRECT SEARCH) < LEAD > * EP1199 1-690-880-31 LEAD (WITH CONNECTOR) < SWITCH > JG1101 1-771-879-11 SWITCH, TACTILE (PUSH ENTER (JOG STICK)) PANEL-L PANEL-R www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 115 DVP-CX995V < RESISTOR > R1101 1-216-825-11 METAL CHIP 2.2K 5% 1/10W R1102 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R1103 1-216-821-11 METAL CHIP 1K 5% 1/10W R1104 1-216-825-11 METAL CHIP 2.2K 5% 1/10W R1105 1-216-825-11 METAL CHIP 2.2K 5% 1/10W R1106 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R1107 1-216-833-11 METAL CHIP 10K 5% 1/10W R1108 1-216-837-11 METAL CHIP 22K 5% 1/10W R1109 1-216-841-11 METAL CHIP 47K 5% 1/10W R1110 1-216-821-11 METAL CHIP 1K 5% 1/10W R1111 1-216-825-11 METAL CHIP 2.2K 5% 1/10W R1112 1-216-825-11 METAL CHIP 2.2K 5% 1/10W R1113 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R1114 1-216-833-11 METAL CHIP 10K 5% 1/10W R1115 1-216-837-11 METAL CHIP 22K 5% 1/10W R1116 1-216-811-11 METAL CHIP 150 5% 1/10W R1117 1-216-811-11 METAL CHIP 150 5% 1/10W R1118 1-216-827-11 METAL CHIP 3.3K 5% 1/10W < ROTARY ENCODER > RE1101 1-475-543-11 ENCODER, ROTARY (DISC/AMS, PUSH ENTER) < SWITCH > S1101 1-771-410-21 SWITCH, TACTILE (OPEN/CLOSE) S1102 1-771-410-21 SWITCH, TACTILE (A DISC EJECT) S1103 1-771-410-21 SWITCH, TACTILE (H) S1104 1-771-410-21 SWITCH, TACTILE (TOP MENU) S1105 1-771-410-21 SWITCH, TACTILE (RETURN) S1106 1-771-410-21 SWITCH, TACTILE (MENU) S1107 1-771-410-21 SWITCH, TACTILE (x) S1108 1-771-410-21 SWITCH, TACTILE (X) S1109 1-771-410-21 SWITCH, TACTILE (DISPLAY) S1110 1-771-410-21 SWITCH, TACTILE (+100) S1111 1-771-410-21 SWITCH, TACTILE (DISC CHANGE) S1112 1-771-410-21 SWITCH, TACTILE (DIRECT SEARCH) ************************************************************ RF TRANSLATION BOARD ********************* < CONNECTOR > CN001 1-750-357-51 CONNECTOR, FFC/FPC (ZIF) 24P CN002 1-817-201-21 CONNECTOR, FFC/FPC 9P CN003 1-784-387-11 CONNECTOR, FFC/FPC 31P ************************************************************ SENSOR BOARD ************** < CAPACITOR > C81 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V < CONNECTOR > * CN81 1-506-486-11 PIN, CONNECTOR 7P * CN82 1-568-940-41 PIN, CONNECTOR 2P CN83 1-506-481-11 PIN, CONNECTOR 2P < PHOTO INTERRUPTER > IC81 8-749-924-18 PHOTO INTERRUPTER RPI-1391 IC82 8-749-924-18 PHOTO INTERRUPTER RPI-1391 IC83 8-749-924-18 PHOTO INTERRUPTER RPI-1391 IC84 8-749-924-18 PHOTO INTERRUPTER RPI-1391 < RESISTOR > R81 1-218-845-11 METAL CHIP 820 0.5% 1/10W R82 1-218-845-11 METAL CHIP 820 0.5% 1/10W R83 1-218-845-11 METAL CHIP 820 0.5% 1/10W R84 1-218-845-11 METAL CHIP 820 0.5% 1/10W R85 1-218-843-11 METAL CHIP 680 0.5% 1/10W ************************************************************ MISCELLANEOUS ************** 2 1-830-199-11 WIRE, FLAT TYPE (33 CORE) 4 1-830-198-11 WIRE, FLAT TYPE (31 CORE) 5 1-830-200-11 WIRE, FLAT TYPE (29 CORE) 56 1-828-394-11 WIRE (FLAT TYPE) (25 CORE) 0102 1-468-894-11 REGULATOR, SWITCHING 0105 1-783-820-31 CORD, POWER 108 1-500-386-11 FILTER, CLAMP (FERRITE CORE) 0501 A-1109-165-A OPTICAL PICK-UP (DBU-3) (SERVICE ASSY) (including spindle motor) 505 1-824-106-51 CABLE, FLEXIBLE FLAT (0.5mm pitch) M601 A-4672-895-A MOTOR (400) ASSY (TABLE) M602 A-4672-895-A MOTOR (400) ASSY (LOADING) M603 1-541-632-12 MOTOR, DC (DOOR) ************************************************************ ACCESSORIES ************ 1-479-273-11 COMMANDER, STANDARD (RM-ASP001) 1-776-279-31 CORD, CONNECTION (AUDIO/VIDEO) 2-592-134-11 MANUAL, INSTRUCTION (ENGLISH) 2-592-134-21 MANUAL, INSTRUCTION (FRENCH) (Canadian) 3-081-834-21 BATTERY COVER (SMK7G) (for RM-ASP001) PANEL-R RF TRANSLATION SENSOR www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 2 DVP-CX995V REVISION HISTORY Clicking the version allows you to jump to the revised page. Also, clicking the version at the upper right on the revised page allows you to jump to the next revised page. Ver. Date Description of Revision 1.0 2005.07 New 1.1 2005.12 Addition of Part No. for AV board and Note (SPM-05086) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com
