Ver 1.0 1999.05 MICROFILM D-V55 SERVICE MANUAL PORTABLE VIDEO CD PLAYER SPECIFICATIONS E Model Chinese Model Model Name Using Similar Mechanism NEW CD Mechanism Type CDM-2901ABA Optical Pick-up Type DAX-01A2 Two LR6 (size AA) batteries:3VDC Battery case (External Batteries): Two LR6 (size AA) batteries:3VDC AC power adaptor (DC IN 6V jack): 220-230 V, 50/60Hz 220 V, 50Hz 220 V, 50/60Hz www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 2 – Specifications ........................................................................... 1 1. SERVICING NOTE ....................................................... 3 2. GENERAL Location and Function of Controls .................................... 4 3. DISASSEMBLY 3-1. Cabinet (Lower) Sub ASSY ....................................... 6 3-2. Lid Sub ASSY, Switch Unit ........................................ 6 3-3. MPEG Board .............................................................. 7 3-4. MD ASSY, IR Board .................................................. 7 3-5. Main Board ................................................................. 8 3-6.Turn Table Motor ASSY (Spindle) (M902), Optical Pick-up (DAX-01A2), Sled Motor ASSY (M901) .......................................... 8 4. SERVICE MODE (TEST MODE) 4-1. How to Enter the Test Mode ....................................... 9 4-2. How to Release the Test Mode ................................... 9 4-3. Each Key Function in Test Mode ............................... 9 5. ELECTRICAL ADJUSTMENTS 5-1. Precautions for Adjustment ...................................... 10 5-2. Before Beginning Adjustment .................................. 10 5-3. Tracking Balance Check ........................................... 10 5-4. Focus Bias Check ......................................................11 6. DIAGRAMS 6-1. Explanation of IC Terminals..................................... 12 6-2. Block Diagram.......................................................... 19 6-3. Printed Wiring Boards (Main Section) ..................... 23 6-4. Schematic Diagram (Main Section) ......................... 27 6-5. Schematic Diagram (MPEG Section) ....................... 34 6-6. Printed Wiring Boards (MPEG Section) .................. 37 7. EXPLODED VIEWS 7-1. Cabinet (Upper) Section ........................................... 42 7-2. Cabinet (Lower) Section........................................... 43 7-3. Optical Pick-up Section (CDM-2901ABA) ............. 44 8. ELECTRICAL PARTS LIST ................................45 SAFETY-RELATED COMPONENT WARNING!! COMPONENTS IDENTIFIED BY MARK ! OR DOTTED LINE WITH MARK !ON THE SCHEMATIC DIAGRAMS AND IN THE PARTS LIST ARE CRITICAL TO SAFE OPERATION. REPLACE THESE COMPONENTS WITH SONY PARTS WHOSE PART NUMBERS APPEAR AS SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUBLISHED BY SONY. Flexible Circuit Board Repairing • Keep the temperature of the soldering iron around 270°C during repairing. • Do not touch the soldering iron on the same conductor of the circuit board (within 3 times). • Be careful not to apply force on the conductor when soldering or unsoldering. Notes on chip component replacement • Never reuse a disconnected chip component. • Notice that the minus side of a tantalum capacitor may be dam- aged by heat. TABLE OF CONTENTS This Compact Disc player is classified as a CLASS 1 LASER product. The CLASS 1 LASER PRODUCT label is located on the bottom exterior. CAUTION Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure. DANGER Invisible laser radiation when open and interlock failed or defeated. Avoid direct exposure to beam. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 3 – SECTION 1 SERVICING NOTE NOTES ON HANDLING THE OPTICAL PICK-UP BLOCK OR BASE UNIT The laser diode in the optical pick-up block may suffer electro- static breakdown because of the potential difference generated by the charged electrostatic load, etc. on clothing and the human body. During repair, pay attention to electrostatic breakdown and also use the procedure in the printed matter which is included in the repair parts. The flexible board is easily damaged and should be handled with care. NOTES ON LASER DIODE EMISSION CHECK The laser beam on this model is concentrated so as to be focused on the disc reflective surface by the objective lens in the optical pick-up block. Therefore, when checking the laser diode emis- sion, observe from more than 30cm away from the objective lens. Before Replacing the Optical pick-up Block Please be sure to check thoroughly the parameters as per the “Optical pick-up Block Checking Procedure” (Part No. : 9-960- 027-11) issued separately before replacing the optical Pick-up block. Note and specifications required to check are given below. • FOK output : IC601 ((£ pin (FOK). When checking FOK, remove the lead wire to disc motor. • S curve P-to-P value : 1.2 – 2Vp-p IC501 !§ pin. When checking S curve P-to-P value, remove the lead wire to disc motor. • RF signal P-to-P value : 0.5 – 0.9Vp-p • Traverse signal P-to-P value : 1.2 – 2.0Vp-p • The repairing grating holder is impossible. Laser Diode Checking Methods During normal operation of the equipment, emission of the laser diode is prohibited unless the upper panel is closed while turning ON the S804 (push switch type). The following two checking methods for the laser diode are operable. Method-1 (In the service mode or normal operation) : Emission of the laser diode is visually checked. 1. Open the upper lid. 2. Push the S804 as shown in Fig. 1-1. 3. Press the fl key. 4. Check the object lens for confirming normal emission of the laser diode. If not emitting, there is a trouble in the automatic power control circuit or the optical pick-up. During normal operation, the laser diode is turned ON about 2.5 seconds for focus searching. Method-2 (In the service mode or normal operation) : Check the value of current flowing in the laser diode. 1. Remove the upper panel. 2. Read the current printed on the rear side of the optical pick-up. (Print on the rear side of the optical pick-up) Fig.1-1 Method to push S804 A C 2 2 1 1 3 9 7 year version month A : less than 48 mA current value date line No. shift No. Fig. 1-2 Digital Voltmeter Connecting Location [MAIN BOARD] (SIDE B) 4 3 2 1 5 6 4 3 2 1 5 6 1 5 10 11 20 B C E B C E B C E BCE BCE R532 C525 C526 R751 C518 D501 C516 R544 L506 R518 IC501 R520 R531 R522 R542 R514 C530 C507 R515 R513 R525 C522 C529 R512 R516 R543 C502 Q504 R510 Q506 Q502 R509 C509 R506 R554 R528 R507 R511 R521 R519 R517 R526 Q501 C519 R523 Q503 Q507 C508 R527 TP512 TP520 TP534 TP540 TP537 TP531 TP536 TP524 TP535(RFO) TP522 (FE) TP523 (TE) TP508 (VC) TP521 TP752 TP810 TP809 TP530 TP525 15 TP524 digital voltmeter TP520 S804 3. Connect a digital voltmeter as shown in Fig. 1-2 4. Press the fl key. 5. Calculate the current value by the reading of the digital voltmeter. Reading of the digital voltmeter V ÷ 4.7 Ω = current value (A) (Example) Reading of the digital voltmeter of 0.2256 V : 0.2256 V ÷ 4.7 Ω = 0.048 (A) = 48 mA 6. Check that the current value is within the following range. +5 • Current value of the label -11 mA(25˚C) Variation by temperature : 0.4mA / ˚C Current increases with temperature increased. Current decreases with temperature decreased. If the current is more than the range above, there is a trouble in the automatic power control circuit or the laser diode is in deterioration. If less than the range, a trouble exists in the automatic power control circuit or the optical pick-up. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 4 – SECTION 2 GENERAL This section is extracted from instruction manual. LOCATION AND FUNCTION OF CONTROLS www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 5 – www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 6 – SECTION 3 DISASSEMBLY Note : Follow the disassembly procedure in the numerical order given. 3-1. CABINET (LOWER) SUB ASSY 3-2. LID SUB ASSY, SWITCH UNIT r The equipment can be removed using the following procedure. MPEG board Cabinet (Lower) sub ASSY Lid sub ASSY, Switch unit Set Main board Turn table motor ASSY (Spindle) (M902), Optical pick-up (DAX-01A2), Sled motor ASSY (M901) MD ASSY, IR board Claw 4 5 2 3 Lid sub ASSY Flexible board 1 Screws (B2x10) Cabinet (lower) sub ASSY Battery lid 6 Claws 6 Claws 7 2 8 Cabinet (upper) sub ASSY Lid sub ASSY Cover, lid Switch unit 1 OPEN 5 Screws (1.7x4) 4 Spring, torsion 3 Bracket (spring) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 7 – 3-3. MPEG BOARD 3-4. MD ASSY, IR BOARD 1 MPEG board CN601 Cabinet (lower) sub ASSY 5 MD ASSY CN501 4 CN504 (black) 3 CN503 (green) 2 CN502 (white) 6 IR board 1 Flexible board Cabinet (lower) sub ASSY www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 8 – 3-5. MAIN BOARD Main board Cabinet (lower) sub ASSY 1 3-6. TURN TABLE MOTOR ASSY (SPINDLE) (M902), OPTICAL PICK-UP (DAX-01A2), SLED MOTOR ASSY (M901) !º 4 5 7 8 2 1 Screws (B1.7) 9 Screws (+P1.4x2.5) 3 Screw (B1.7x6) 6 Screw Screw ASSY, Feed Spring, sled Optical pick-up (DAX-01A2) Turn table motor ASSY (Spindle) (M902) Chassis Sled motor ASSY (M901) Rack www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 9 – SECTION 4 SERVICE MODE (TEST MODE) • In this set, there are two test modes; CD-DA Test Mode and VIDEO CD Test Mode. 4-1. How to Enter the Test Mode 1. Disconnect external power (no current is applied to the set). 2. Bridge the TAP801 (TEST) on the MAIN Board with a solder. (IC801 (∞ (TEST) pin is shorted to the ground.) 3. Connect the external power. 4. The CD-DA Test Mode is activated. (LCD display varies in 5- ways, and its 5-way display is repeated.) 5. Before connecting external power in step 3, if π (STOP) key was pressed, the mode is switched to VIDEO CD Test Mode. (On the LCD, all segments are displayed, and the video monitor becomes 100% white.) 4-2. How to Release the Test Mode 1. Always disconnect external power, and break the solder bridge of TAP801 (TEST) on the MAIN Board. 2. Thus, the set become ready for normal operation. 4-3. Each key Function in Test Mode 1. CD-DA Test Mode 2. VIDEO CD Test Mode – MAIN Board – (Side A) Fig.4-1 Test terminal location and connecting position Switches Description π Stop processing Press once: Initialize, Average Correct fl Press twice: Auto Focus (PLAY/PAUSE) Press 3 times: Focus Auto Gain Press 4 times: Tracking Auto Gain Press 5 times: All Servo ON, Mute OFF Repeat once more the processing currently SELECT selected with fl (PLAY/PAUSE) key. ± Move optical pick-up toward outside track (NEXT) ≠ Move optical pick-up toward inside track (PREV) ˆ Turn off the Mute (RETURN) ESP Turn on/off the ESP (fast speed play, when ON) REPEAT/ Tracking Gain up/normal switching ENTER + Raise K13* by one step after Focus Auto Gain MENU Raise K23** by one step after Tracking Auto Gain – Lower K13* by one step after Focus Auto Gain MENU Lower K23** by one step after Tracking Auto Gain Switches Description π Go to CD-DA Test Mode SELECT Video system reset (return to 100% white screen) TAP801 (TEST) CN801 CN501 Monitor IN Video monitor Video OUT (J901) J901 * Coefficient of Focus Gain ** Coefficient of Tracking Gain www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 10 – SECTION 5 ELECTRICAL ADJUSTMENTS 5-1. Precautions for Adjustment 1. Before beginning adjustment, set the equipment to service mode. After the completion of adjustment, be sure to reset the service mode. For more information, see “Service Mode (Test Mode)” on page 9. 2. Perform adjustments in the order given. 3. Use YEDS-18 disc (Part No.: 3-702-101-01) unless otherwise indicated. 4. Power supply voltage requirement: DC6 V HOLD switch: OFF VOLUME control: Minimum RESUME switch: OFF 5-2. Before Beginning Adjustment Set the equipment to service mode (See page 9) and check the following. If there is an error, repair the equipment. • Checking of the sled motor 1. Open the upper lid. 2. Press the ± and ≠ keys and check that the optical pick- up can move smoothly without sluggishness or abnormal noise in innermost periphery n outermost periphery n innermost periphery. ± : The optical pick-up moves outwardly. ≠ : The optical pick-up moves inwardly. • Checking of the Focus serching 1. Open the upper lid. 2. Press the fl key twice. (Focus searching operation is activated continuously.) 3. Check the object lens of the optical pick-up for smooth up/ down motion without sluggishness or abnormal noise. 4. Press the π key. Check that focus searching operation is deactivated. If not, again press the π key slightly longer. 5-3. Tracking Balance Check Condition: • Hold the set in horizontal state. Connection: 4 3 2 1 5 6 4 3 2 1 5 6 1 5 10 11 20 B C E B C E B C E BCE BCE R532 C525 C526 R751 C518 D501 C516 R544 L506 R518 IC501 R520 R531 R522 R542 R514 C530 C507 R515 R513 R525 C522 C529 R512 R516 R543 C502 Q504 R510 Q506 Q502 R509 C509 R506 R554 R528 R507 R511 R521 R519 R517 R526 Q501 C519 R523 Q503 Q507 C508 R527 TP512 TP520 TP534 TP540 TP537 TP531 TP536 TP524 TP535(RFO) TP522 (FE) TP523 (TE) TP508 (VC) TP521 TP752 TP810 TP809 TP530 TP525 15 TP523(TE) oscillscope (DC range) TP508(VC) Checking Method: 1. Connect the oscilloscope to TP523 (TE) and TP508 (VC) on the MAIN board. 2. Set the equipment to service mode stop state. (See page 9.) 3. Press the fl key once. 4. Move the optical pick-up to the center by pressing the ± and ≠ keys. 5. Put the disc (YEDS-18). 6. Press the fl key twice. From focus searching, focus is turned ON while entering CLV drawing-in mode. Tracking and sled are turned OFF. 7. Confirm that a waveform on the oscilloscope is vertically symmetric against 0 V. 8. Stop removing of the disc motor by pressing the π key. 9. After the completion of check, reset service mode. (See page 9.) MAIN board (Side B) A B 0 V A B 0 V 1.2 – 2 Vp-p A=B A=B Note: Take long sweep time for easy monitoring. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 11 – 5-4. Focus Bias Check Condition: • Hold the set in horizontal state. Connection: 4 3 2 1 5 6 4 3 2 1 5 6 1 5 10 11 20 B C E B C E B C E BCE BCE R532 C525 C526 R751 C518 D501 C516 R544 L506 R518 IC501 R520 R531 R522 R542 R514 C530 C507 R515 R513 R525 C522 C529 R512 R516 R543 C502 Q504 R510 Q506 Q502 R509 C509 R506 R554 R528 R507 R511 R521 R519 R517 R526 Q501 C519 R523 Q503 Q507 C508 R527 TP512 TP520 TP534 TP540 TP537 TP531 TP536 TP524 TP535(RFO) TP522 (FE) TP523 (TE) TP508 (VC) TP521 TP752 TP810 TP809 TP530 TP525 15 TP535 (RFO) 2kΩ oscillscope (AC range) TP508 (VC) Checking Method: 1. Connect the oscilloscope to TP535 (RFO) and TP508 (VC) on the MAIN board. 2. Set the equipment to service mode stop state. (See page 9.) 3. Press the fl key once. 4. Move the optical pick-up to the center by pressing the ± and ≠ keys. 5. Put the disc (YEDS-18). 6. Press the fl key four times. From focus searching, focus is turned ON while entering CLV drawing-in mode. Both tracking and sled are turned ON. 7. Check the oscilloscope waveform is as shown below. A good eye pattern means that the diamond shape (≈) in the center of the waveform can be clearly distinguished. RF SIGNAL REFERENCE WAVEFORM (EYE PATTERN) VOLT/DIV : 200 mV (With the 10:1 probe in use) TIME/DIV : 500 ns To watch the eye pattern, set the oscilloscope to AC range and in- crease the vertical sensitivity of the oscilloscope for easy watching. MAIN board (Side B) 8. Stop revolving of the disc motor by pressing the π key. 9. After the completion of check, reset service mode. (See page 9.) RF level 0.5 – 0.9 Vp-p www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 12 – SECTION 6 DIAGRAMS 6-1. EXPLANATION OF IC TERMINALS • MAIN BOARD (1/2) IC601 CXD2545Q (DIGITAL SIGNAL PROCESSOR, FOCUS/TRACKING/SLED SERVO, EFM COMPARATOR) Pin No. Pin name I/O Description 1 SRON O Sled servo drive PWM signal output terminal. Not used (open) 2 SRDR O Sled servo drive PWM signal (-) output to the MPC17A51VMEL (IC502). 3 SFON O Sled servo drive PWM signal output terminal. Not used (open) 4 TFDR O Tracking servo drive PWM signal (-) output to the MPC17A51VMEL (IC502). 5 TRON O Tracking servo drive PWM signal output terminal. Not used (open) 6 TRDR O Tracking servo drive PWM signal (+) output to the MPC17A51VMEL (IC502). 7 TFON O Tracking servo drive PWM signal output terminal. Not used (open) 8 FFDR O Focus servo drive PWM signal (+) output to the MPC17A51VMEL (IC502). 9 FRON O Focus servo drive PWM signal output terminal. Not used (open) 10 FRDR O Focus servo drive PWM signal (-) output to the MPC17A51VMEL (IC502). 11 FFON O Focus servo drive PWM signal output terminal. Not used (open) 12 VCOO O Oscillator circuit output terminal for analog PLL of the playback EFM. 13 VCOI I Oscillator circuit input terminal for analog PLL of the playback EFM. 14 TEST I Input terminal for the test (fixed at “L”). 15 DVSS – Ground terminal (digital system). 16 TES2 I Input terminal for the test (fixed at “L”). 17 TES3 I Input terminal for the test (fixed at “L”). 18 PDO O Charge-pump output terminal for analog PLL of the playback EFM. Not used (open) 19 VPCO O PLL charge-pump output terminal for the variable pitch. Not used (open) 20 VCKI I Master clock signal (16.9344 MHz) input from the D/A converter (IC322) for the variable pitch. 21 AVD2 – Power supply terminal (+3.3V) (analog system). 22 IGEN I Power supply terminal (+3.3V) (for operational amplifier). 23 AVS2 – Ground terminal (analog system). 24 ADIO I Input terminal for the A/D converter. Not used (open) 25 RFC O Output terminal of the operational amplifier. Not used (open) 26 RFDC I RF signal (DC level) input terminal for the digital servo process. 27 TE I Tracking error signal input from the CXA1791N (IC501). 28 SE I Sled error signal input from the CXA1791N (IC501). 29 FE I Focus error signal input from the CXA1791N (IC501). 30 VC I Middle point voltage (+1.65V) input from the CXA1791N (IC501). 31 FILO O Filter output terminal for master clock of the playback master PLL. 32 FILI I Filter input terminal for master clock of the playback master PLL. 33 PCO O Phase comparison output terminal for master clock of the playback EFM master PLL. 34 CLTV I Internal VCO control voltage input of the playback master PLL. 35 AVS1 – Ground terminal (analog system). 36 RFAC I RF signal (AC level) input terminal for the EFM demodulator. 37 BIAS I Constant current input terminal of the playback EFM asymmetry circuit. 38 ASYI I Playback EFM asymmetry comparator voltage input terminal. 39 ASYO O Playback EFM full-swing output terminal. 40 AVD1 – Power supply terminal (+3.3V) (analog system). 41 DVDD – Power supply terminal (+3.3V) (digital system). 42 ASYE I Playback EFM asymmetry circuit on/off selection input terminal (fixed at “H”). 43 PSSL I Audio data output mode selection input terminal (fixed at “L”). 44 WDCK O Word clock signal (88.2 kHz) output terminal. Not used (open) 45 LRCK O L/R sampling clock signal (44.1 kHz) output to the D-RAM controller (IC681) and MPEG audio/video decoder (IC701). www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 13 – Pin No. Pin name I/O Description 46 DATA O DA16 output when PSSL=“H”, 48-bit slot serial data output when PSSL=“L” (PSSL (pin $£)=fixed at “L”) Serial data output to the D-RAM controller (IC681) and MPEG audio/video decoder (IC701). 47 BCLK O DA15 output when PSSL=“H”, 48-bit slot bit clock signal output when PSSL=“L” (PSSL (pin $£)=fixed at “L”) Bit clock signal (2.8224 MHz) output to the D-RAM controller (IC681) and MPEG audio/video decoder (IC701). 48 64 DATA O DA14 output when PSSL=“H”, 64-bit slot serial data output when PSSL=“L” (PSSL (pin $£)=fixed at “L”). Not used (open) 49 64 BCLK O DA13 output when PSSL=“H”, 64-bit slot bit clock signal output when PSSL=“L” (PSSL (pin $£)=fixed at “L”). Not used (open) 50 64 LRCK O DA12 output when PSSL=“H”, 64-bit slot L/R sampling clock signal output when PSSL=“L” (PSSL (pin $£)=fixed at “L”). Not used (open) 51 GTOP O DA11 output when PSSL=“H”, GTOP signal output when PSSL=“L” (PSSL (pin $£)=fixed at “L”). Not used (open) 52 XUGF O DA10 output when PSSL=“H”, XUGF signal output when PSSL=“L” (PSSL (pin $£)=fixed at “L”). Not used (open) 53 XPLCK O DA09 output when PSSL=“H”, XPLCK signal output when PSSL=“L” (PSSL (pin $£)=fixed at “L”). Not used (open) 54 GFS O DA08 output when PSSL=“H”, GFS (guard frame sync) signal output when PSSL=“L” (PSSL (pin $£)=fixed at “L”). Not used (open) 55 RFCK O DA07 output when PSSL=“H”, RFCK (read frame clock) signal output when PSSL=“L” (PSSL (pin $£)=fixed at “L”). Not used (open) 56 C2PO O DA06 output when PSSL=“H”, C2PO signal output when PSSL=“L” (PSSL (pin $£)=fixed at “L”) C2PO signal output to the D-RAM controller (IC680) and MPEG audio/video decoder (IC901). 57 XRAOF O DA05 output when PSSL=“H”, XRAOF (RAM over flow) signal output when PSSL=“L” (PSSL (pin $£)=fixed at “L”). Not used (open) 58 MNT3 O DA04 output when PSSL=“H”, MNT3 (monitor 3) signal output when PSSL=“L” (PSSL (pin $£)=fixed at “L”). Not used (open) 59 MNT2 O DA03 output when PSSL=“H”, MNT2 (monitor 2) signal output when PSSL=“L” (PSSL (pin $£)=fixed at “L”). Not used (open) 60 MNT1 O DA02 output when PSSL=“H”, MNT1 (monitor 1) signal output when PSSL=“L” (PSSL (pin $£)=fixed at “L”). Not used (open) 61 MNT0 O DA01 output when PSSL=“H”, MNT0 (monitor 0) signal output when PSSL=“L” (PSSL (pin $£)=fixed at “L”). Not used (open) 62 XTAI I Master clock signal (16.9344 MHz) input from the D/A converter (IC322). 63 XTAO O Master clock output terminal (16.9344 MHz). Not used (open) 64 XTSL I Master clock selection input terminal (fixed at “L”). 65 DVSS – Ground terminal (digital system). 66 FSTI I 2/3 divider input terminal of pins ^™ (XATI) and ^£ (XTAO). 67 FSTO O 2/3 divider output terminal of pins ^™ (XATI) and ^£ (XTAO). 68 C4M O 4.2336 MHz clock signal output terminal. Not used (open) 69 C16M O 16.9344 MHz clock signal output terminal. Not used (open) 70 MD2 I Digital out on/off control signal input terminal Fixed at “H” in this set. 71 DOUT O Digital signal (for coaxial out and optical out) output terminal. Not used (open) 72 EMPH O Emphasis control signal output terminal. Not used (open) 73 WFCK O Write frame clock signal output terminal. Not used (open) 74 SCOR O Sub-code sync (S0+S1) detection signal output to the D-RAM controller (IC681) and system controller (IC801). 75 SBSO O Sub-code P-W serial data output terminal. Not used (open) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 14 – Pin No. Pin name I/O Description 76 EXCK I Sub-code P-W serial data reading clock signal input terminal. Not used (fixed at “L”) 77 SUBQ O Sub-code Q data signal output to the system controller (IC801). 78 SQCK I Sub-code Q data reading clock signal input from the system controller (IC801). 79 MUTE I Mute signal input terminal. Fixed at “L” in this set 80 SENS O Internal status (SENSE) signal output to the system controller (IC801). ______ 81 XRST I Reset signal input from the system controller (IC801) “L”: reset For several hundreds msec. after the power supply rises,“L” is input, then it changes to “H” 82 DIRC I 1-track jump mode input terminal Not used (fixed at “H”) 83 SCLK I Sense serial data reading clock signal input from the system controller (IC801). 84 DFSW I Defect on/off select signal input terminal. Not used (fixed at “L”) 85 ATSK I Input terminal for the anti-shock. Not used (fixed at “L”) 86 DATA I Serial data input from the system controller (IC801). 87 XLAT I Serial data latch pulse signal input from the system controller (IC801). 88 CLOK I Serial data transfer clock signal input from the system controller (IC801). 89 COUT O Track number count signal output terminal. Not used (open) 90 DVDD – Power supply terminal (+3.3V) (digital system). 91 MIRR O Mirror detection signal output terminal. Not used (open) 92 DFCT O Defect signal output terminal. Not used (open) 93 FOK O Focus OK signal output terminal. Not used (open) 94 FSW O Selection signal output terminal of the output filter for spindle motor. Not used (open) 95 MON O Spindle motor on/off control signal output terminal. Not used (open) 96 MDP O Spindle servo control signal output. 97 MDS O Spindle servo control signal output. 98 LOCK O GFS is sampled by 460 Hz. “H” output when GFS is “H” Not used (open) 99 SSTP I Detection input from the sled limit-in detect switch (S901). The optical pick-up is inner position when “H” 100 SFDR O Sled servo drive PWM signal (+) output to the MPC17A51VMEL (IC502). www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 15 – • MAIN BOARD IC801 MSM65354-418GS-BK4 (SYSTEM CONTROLLER, LCD DRIVER, KEY CONTROL) Pin No. Pin name I/O Description 1-4 COM1-4 O Common drive signal output to the liquid crystal display. 5-19 SEG0-14 O Segment drive signal output to the liquid crystal display. 20-36 NC – Not used (open). 37 AGND – Ground terminal (analog system). 38 DC IN JACK I DC IN 6V jack (J801) detection input terminal. “L”: plug in 39 DOOR OPEN I CD lid open/close detection switch (S804) input terminal The stop status is reset with the falling edge of input signal. “H”: CD lid open, “L”: CD lid close 40 KEY IN1 I Key input terminal (A/D input). 41 XRM KEY IN I Remote control key input terminal (A/D input). 42 DC CHK I DC in voltage detection input terminal (A/D input) Also used for DC IN detection 43 NTSC/PAL I Video system select switch (S803) input terminal “L”: NTSC, “H”: PAL 44 BATT CHK I Battery check terminal. 45 KEY IN2 I Key input terminal (A/D input). 46 VRH I Reference voltage input terminal (+3.3V) (for A/D converter). 47 AVDD – Power supply terminal (+3.3V) (analog system). 48 DBB CTL1 O MEGA BASS on/off control signal output to the BA3574BFS (IC361). “L”: MEGA BASS on (level-1 and level-2) 49 AU-MUTE O Analog line mute control signal output terminal . “H”: mute on ____________ 50 XAU-RESET O Reset signal output to the CXD2545Q (IC601) and D-RAM controller (IC681). “L”: reset __________ 51 XV-RESET O Reset signal output to the MPEG audio/video decoder (IC701) and video encoder (IC721). “L”: reset 52 HOLD I HOLD switch (S802) input terminal. “L”: hold off, “H”: hold on 53 RESUME I RESUME switch (S801) input terminal. “L”: resume off, “H”: resume on 54 XDSPLT O Serial data latch pulse signal output to the CXD2545Q (IC601). 55 XDACLT O Serial data latch pulse signal output to the D/A converter (IC322). 56 V-POWER O Video CD system power supply on/off control signal output terminal. “L”: power on 57 AU-POWER O Audio CD system power supply on/off control signal output terminal. “L”: power on 58 ESP-POWER O Control signal output to the ESP (Electronic Shock Protection) circuit. 59 TRVCTL O Tracking gain control signal output terminal. 60 TRV3 O 61 TRV2 O Tracking balance control signal output terminal. 62 TRV1 O 63 TRV0 O ______ 64 XSOE O Serial data output enable signal output to the D-RAM controller (IC681). 65 DSP-SUBQ I Sub-code Q data signal input from the CXD2545Q (IC601). 66 DSP-SBQCLK O Sub-code Q data reading clock signal output to the CXD2545Q (IC601). 67 REMOTE I Sircs remote control signal input from the remote control receiver (IC1). 68 DSP-DATA O Serial data output to the CXD2545Q (IC601) and D/A converter (IC322). 69 DSP-SENS I Internal status (SENSE) signal input from the CXD2545Q (IC601). 70 DSP-CLK O Serial data transfer clock signal output to the CXD2545Q (IC601) and D/A converter (IC322). 71 DSP-SNSCLK O Sense serial data reading clock signal output to the CXD2545Q (IC601). 72 VDD – Power supply terminal (+3.3V) (digital system). 73 BEEP O Beep sound drive signal output terminal. 74 C2PO O C2PO signal control output to the D-RAM controller (IC681). “L”: stop mode, “H”: searching 75 ESP-CLK O Serial data transfer clock signal output to the D-RAM controller (IC681). www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 16 – Pin No. Pin name I/O Description 76 ESP-DATA O Serial data output to the D-RAM controller (IC681). 77 ESP-LT O Serial data latch pulse signal output to the D-RAM controller (IC681). 78 ESP-SENSE I Sense serial data input from the D-RAM controller (IC681). ____________ 79 XLASERCTL O Laser diode on/off control signal output to the CXA1791N (IC501). “L”: laser on 80 DSP-SCOR I Sub-code sync (S0+S1) detection signal input from the CXD2545Q (IC601). 81 OSC1 O Main system clock output terminal (4.19 MHz). 82 OSC0 I Main system clock input terminal (4.19 MHz). 83 GND – Ground terminal (digital system). 84 XT I Sub system clock input terminal. Not used (fixed at “L”) 85 XTO O Sub system clock output terminal. Not used (open) 86 A-SELECT O Selection signal output to the DATA, BCLK, LRCK signal select switch (IC321) . “L”: CD play, “H”: video CD play 87 XIRCTL O Power supply on/off control signal for the remote control receiver (IC1). “L”: power on 88 SYS XMT RQ O Communication request signal output to the MPEG audio/video decoder (IC701). 89 SYS RCV RDY O Ready signal output to the MPEG audio/video decoder (IC701). 90 MPG XMT RQ I Communication request signal input from the MPEG audio/video decoder (IC701). 91 ESS-DATAO O Serial data output to the MPEG audio/video decoder (IC701). 92 ESS-DATAI I Serial data input from the MPEG audio/video decoder (IC701). 93 ESS-CLK O Serial data transfer clock signal output to the MPEG audio/video decoder (IC701). ______ 94 RESET I System reset signal input from the reset signal generator (IC802). “L”: reset For several hundreds msec. after the power supply rises, “L” is input, then it changes to “H” _____ 95 TEST I Service mode setting terminal. The stop status is reset with the falling edge of input signal “L”: service mode, Normally: “H” 96 DBB CTL2 O MEGA BASS level control signal output to the BA3574BFS (IC361) . “L”: MEGA BASS level-1, “H”: MEGA BASS level-2 97 VDDL – 98 VDD1 – Power supply output for the liquid crystal display bias. 99 VDD2 – 100 VDD3 – www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 17 – • MPEG BOARD IC701 ES3210 (MPEG AUDIO/VIDEO DECODER) Pin No. Pin name I/O Description 1 VCC – Power supply terminal (+3.3V). _______ 2 DRAS B O Row address strobe signal output to the D-RAM (IC703) . “L” active _______ 3 DWE B O Write enable signal output to the D-RAM (IC703). “L” active 4 – 12 MA0 – 8 O Address signal output to the D-RAM (IC703). 13 – 28 DBUS0 – 15 I/O Two-way data bus with the D-RAM (IC703). ________ 29 RESET B I Reset signal input from the system controller (IC801). “L”: reset 30 VSS – Ground terminal. 31 VCC – Power supply terminal (+3.3V). 32 – 39 YUV0 – 7 O Video data output to the video encoder (IC721). (YUV; Y: luminance signal, UV: Screen video interface chrominance data bus) 40 VSSCN B O Vertical synchronous signal output to the video encoder (IC721). 41 HSSCN B O Horizontal synchronous signal output to the video encoder (IC721). 42 CLK I System clock signal input terminal Not used (open). 43 PCLK2XSCN I System clock signal (27 MHz) input from the video encoder (IC721). 44 PCKLQSCN O Pixel clock qualifier output for the screen video interface Not used (open). 45 AUX0 O Sub control signal output terminal Not used (open). 46 AUX1 I Serial data input from the system controller (IC801). 47 AUX2 O Serial data output to the system controller (IC801). 48 AUX3 O NTSC/PAL mode selection signal output to the video encoder (IC721). “L”: NTSC, “H”: PAL 49 AUX4 I C2PO signal input from the CXD2545Q (IC601). 50 VSS – Ground terminal. 51 VCC – Power supply terminal (+3.3V). 52 AUX6 O Communication request signal output to the system controller (IC801). 53 AUX5 I Ready signal input from the system controller (IC801). 54 AUX7 I Communication request signal input from the system controller (IC801). 55 – 62 LD0 – 7 I Data input from the program ROM (IC702). ______ 63 LWR B O Write enable signal output terminal. “L” active Not used _______ 64 LOE B O Output enable signal output to the program ROM (IC702). “L” active _______ 65 LCS3 B O Chip select signal output to the program ROM (IC702). “L” active _______ 66 LCS1 B I Serial data transfer clock signal input from the system controller (IC801). “L” active _______ 67 LCS0 B O Chip select signal output terminal. “L” active Not used (open) 68 – 79 LA0 – 11 O Address signal output to the program ROM (IC702). 80 VSS – Ground terminal. 81 VPP – Power supply terminal (+5V) (digital system). 82 – 87 LA12 – 17 O Address signal output to the program ROM (IC702). 88 AUDIOCLK I Audio master clock signal (16.9344 MHz) input from the D/A converter (IC322). 89 AOUT O Audio interface serial data output to the D/A converter (IC322). 90 TBCK O Bit clock signal (2.8224 MHz) output to the D/A converter (IC322). 91 ATFS O L/R sampling clock signal (44.1 kHz) output to the D/A converter (IC322). ______ 92 DOE B O Output enable signal output to the D-RAM (IC703). “L” active 93 AIN I Audio interface serial data input terminal. Not used (open) 94 RBCK I Audio interface bit clock signal (2.8224 MHz) input terminal. Not used (open) 95 ARFS I Audio interface L/R sampling clock signal (44.1 kHz) input terminal. Not used (open) 96 TDMCLK I Bit clock signal (2.8224 MHz) input from the CXD2545Q (IC601). 97 TDMDR I Serial data input from the CXD2545Q (IC601). 98 TDMFS I L/R sampling clock signal (44.1 kHz) input from the CXD2545Q (IC601). _______ 99 DCAS B O Column address strobe signal output to the D-RAM (IC703). “L” active 100 VSS – Ground terminal. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 18 – • MPEG BOARD IC721 TC90A07U (VIDEO ENCODER) Pin No. Pin name I/O Description 1 MIFH I Horizontal synchronous signal input from the MPEG audio/video decoder (IC701). 2 MIFFL I Vertical synchronous signal input from the MPEG audio/video decoder (IC701). 3 MIFFR O Frame synchronous signal output terminal. Not used (open) 4 VBLNKI I Video blanking signal input terminal. “L”: blanking 5 VDD – Power supply terminal (+3.3V) (digital system). 6 GND – Ground terminal (digital system). 7 YCDI0 I 8 bit pixel data (LSB) input from the MPEG audio/video decoder (IC701). 8- 13 YCDI1 – YCDI6 I 8 bit pixel data input from the MPEG audio/video decoder (IC701). 14 YCDI7 I 8 bit pixel data (MSB) input from the MPEG audio/video decoder (IC701). 15 MODE I NTSC/PAL mode selection signal input from the MPEG audio/video decoder (IC701). “L”: NTSC, “H”: PAL 16 VBLNKO O Video blanking signal output terminal. 17 VDD – Power supply terminal (+3.3V) (digital system). 18 GND – Ground terminal (digital system). 19 CLPF I Low-pass filter on/off control signal input for the internal CbCr. “L”: on, “H”: off Fixed at “L” in this set 20 BF O Burst flag pulse output terminal. Not used (open) 21 BLK O Blanking signal output terminal. Not used (open) 22 FLD O Field discrimination signal output terminal. “L”: odd number field, “H”: even number field Not used (open) 23 BIAS2 – Connect a capacitor for the D/A converter bias. 24 BIAS1 – Connect a capacitor for the D/A converter bias. 25 VREF I Reference voltage input terminal (for D/A converter). 26 AGND – Ground terminal (analog system for D/A converter). 27 YOUT O Analog Y signal (luminance signal) output terminal. Not used (open) 28 AVCC – Power supply terminal (+3.3V) (analog system for D/A converter). 29 COUT O Analog C signal (chroma signal) output terminal. Not used (open) 30 AGND – Ground terminal (analog system for D/A converter). 31 CVOUT O Analog composite video signal output terminal. 32 AVCC – Power supply terminal (+3.3V) (analog system for D/A converter). 33 CSYNC O Composite synchronous signal output terminal. Not used (open) 34 HSYNC O Horizontal synchronous signal output terminal. Not used (open) 35 VSYNC O Vertical synchronous signal output terminal. Not used (open) 36 TMS3 I Mode setting terminal. Normally fixed at “H” 37 VDD – Power supply terminal (+3.3V) (digital system). 38 CK27I I System clock input terminal (27 MHz). 39 XO O System clock output terminal (27 MHz). 40 GND – Ground terminal (digital system). 41 TMS2 I Mode setting terminal. Normally fixed at “H” 42 CK27O O System clock signal (27 MHz) output to the MPEG audio/video decoder (IC701). 43 TMS1 I Reset signal input from the system controller (IC801) . “L”: reset 44 TMS0 I Video output mode setting terminal. “L”: normal output mode, “H”: color bar output mode www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 19 – – 20 – – 22 – – 21 – D-V55 6-2. BLOCK DIAGRAM • Signal path. J : CD L : VIDEO w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 25 – – 26 – – 23 – – 24 – D-V55 6-3. PRINTED WIRING BOARDS (MAIN SECTION) IC601 C-12 IC602 E-17 IC681 C-17 IC682 D-3 IC801 F-13 IC802 D-13 Q101 C-17 Q201 C-17 Q351 E-17 Q352 E-17 Q353 E-17 Q361 F-17 Q362 G-16 Q363 G-16 Q412 E-4 Q413 F-9 Q421 F-4 Q422 F-4 Q501 C-15 Q502 B-14 Q503 B-14 Q504 B-14 Q505 B-13 Q506 C-14 Q507 C-14 Q601 D-12 Q801 E-14 Q802 F-14 Q812 E-13 D101 B-17 D102 G-16 D201 B-17 D202 H-16 D301 H-16 D302 H-16 D351 E-17 D361 F-17 D401 F-11 D402 G-11 D404 E-12 D405 F-9 D411 E-4 D412 E-16 D421 F-16 D422 F-4 D501 C-14 D601 D-12 D681 D-18 D682 D-16 D801 E-12 IC1 A-1 IC321 D-18 IC322 E-18 IC361 F-17 IC411 F-16 IC421 F-16 IC501 B-15 IC502 C-15 IC503 C-14 IC504 D-14 Ref. No. Location Ref. No. Location r Semiconductor Location 1 5 10 6 1 2 5 10 15 20 24 23 1 5 2 10 15 20 23 24 1 14 1 5 9 13 18 22 14 26 E C B S D G 1 CN802 C418 R426 R429 C428 C429 R425 C414 C417 C423 C427 D411 C683 L411 TAP802 CN501 IC682 TP301 S802 C366 C364 C808 C809 TAP502 CN503 C752 M901 SLED MOTOR S901 (LIMIT) C619 C426 TAP501 TAP801 (TEST) FB804 RED RED WHT WHT BLK BLK Q421 Q412 CN504 CN801 CN502 1 2 1 2 TP519 TP528 TP526 TP518 TP532 TP529 TP527 C330 C328 TP1 TP3 TP2 IC1 C1 1 2 3 4 OFF ON HOLD BLK ORG GRY GRY M BLK GRY GRY ORG 1 2 BLK RED A MPEG BOARD CN901 M902 SPINDLE MOTOR M RED BLK 1-674-189- 1-674-189- S801 RESUME OPTICAL PICK-UP SWITCH UNIT BLOCK DAX-01A2 11 (11) 1-674-190- [MAIN BOARD] (SIDE A) [IR BOARD] (SIDE A) [IR BOARD] (SIDE B) 4 3 2 1 5 6 4 3 2 1 5 6 1 5 10 11 20 BCE B C E B C E B C E B C E B C E BCE BCE BCE BCE 6 5 4 3 2 1 1 5 10 15 20 19 25 30 35 11 10 5 22 20 15 33 30 25 23 44 40 1 12 34 35 5 1 10 15 20 25 30 35 31 40 45 50 55 51 60 65 70 75 80 85 81 90 95 100 10 12 5 1 13 15 20 24 1 7 5 8 14 10 1 5 10 11 15 20 1 5 8 9 12 16 1 2 4 5 1 2 4 5 1 4 5 8 BCE B C E 5 4 3 2 1 B C E 1 4 5 8 1 4 5 8 BCE BCE R817 R821 R822 Q812 R824 C816 R825 R820 R823 R427 R428 C430 D682 R424 R414 IC421 R547 R551 C422 R404 R423 L401 L402 FB807 D412 D401 R540 IC681 C618 FB808 R556 D301 C685 C369 R403 C415 R415 R418 C413 D404 C601 C331 C401 TB402 R354 R826 R416 C412 R617 R612 R417 R422 D402 D351 R402 R401 IC802 R532 R555 R611 C527 C525 C533 C528 C526 C532 R538 IC321 IC601 IC801 IC322 C511 IC602 R534 TAP603 R549 C534 C536 C371 C372 R365 R107 C375 L322 R751 L321 C504 C512 C514 C520 IC411 R620 R621 C518 D501 C516 Q352 C353 C812 R806 C803 C361 Q361 R613 D361 R618 C351 R553 R529 R544 D681 R207 Q363 R206 Q362 FB202 R602 C106 C325 R321 R601 C327 C416 IC504 L506 R814 C613 R815 FB803 D601 D801 C801 R518 C204 R681 R606 R535 R364 R811 R807 IC501 C807 R520 D102 D101 C802 R604 R102 C322 C323 C605 C682 FB102 Q802 X321 C505 C425 C612 C805 Q353 R531 R522 R550 R530 R603 C501 R351 R542 R558 TAP421 R514 D421 X801 C530 C507 R515 C616 R204 R513 C506 R525 C522 C529 IC502 R536 R512 R516 C513 R543 C502 R805 C370 R502 R504 R501 L602 Q504 C365 R510 C362 Q506 Q502 C503 C205 R819 C751 L502 L504 FB802 R802 R619 C368 C105 R801 C101 Q505 C615 D302 D201 R545 C607 C523 R816 FB751 Q201 C326 C804 R505 R353 C606 R509 R548 C608 R508 C509 C535 R506 R554 C517 R528 R524 R557 R205 R503 FB682 L801 L324 R104 C201 FB101 L501 R804 R803 R810 R812 R615 C811 R809 C367 R752 C521 R103 C810 C104 R507 R754 C684 C203 R511 Q801 R106 C510 R537 R362 R363 R521 C206 R201 FB201 R101 C602 R818 C603 R519 R517 FB681 TAP411 R526 FB683 R323 R614 C321 TAP602 R813 L601 C424 FB801 R352 R607 C611 Q601 R609 R608 C609 D202 C515 C421 C617 R322 C102 Q501 FB321 C352 FB805 L323 C519 R421 C604 R541 R610 R523 R539 R605 R546 C103 R105 L505 C806 Q503 Q101 R616 Q507 C324 R413 R203 R202 R753 C508 Q351 L503 C411 TAP601 FB806 IC503 C329 C202 R527 FB301 IC361 TP835 TP833 TP831 TP830 TP827 TP825 TP817 TP405 TP826 TP803 TP816 TP818 TP802 TP821 TP822 TP823 TP824 TP815 TP404 TP403 TB401 TP601 TP602 TP603 TP604 TP605 TP607 TP606 TP609 TP608 TP610 TP517 TP401 TP422 TP411 TP421 TP414 TP412 TP351 TP644 TP637 TP633 TP635 TP639 TP631 TP629 TP632 TP634 TP641 TP643 TP627 TP630 TP626 TP640 TP636 TP352 TP819 TP820 TB404 TB403 TP303 TP365 TP364 TP363 TP304 TP326 TP324 TP325 TP840 TP323 TP322 TP638 TP642 TP516 TP515 TP504 TP503 TP501 TP502 TP683 TP682 TP681 TP813 TP811 TP511 TP510 TP506 TP509 TP505 TP512 TP520 TP533 TP539 TP534 TP540 TP537 TP538 TP531 TP536 TP524 TP535(RFO) TP522 (FE) TP523 (TE) TP514 TP507 TP513 TP508 (VC) TP812 TP684 TP685 TP686 TP628 TP101 TP751 TP201 TP521 TP752 TP810 TP809 TP530 TP525 TP611 TP613 TP614 TP612 TP615 TP616 TP617 TP618 TP619 TP620 TP621 TP624 TP623 TP622 TP625 TP302 TP102 TP202 TP801 TP838 TP836 TP834 TP807 TP808 TP805 TP806 TP804 TP839 TP837 TP832 TP829 TP828 S804 (OPEN SW) 5 1 10 15 20 25 30 31 35 40 45 50 51 55 60 65 70 75 80 81 85 90 95 100 J901 AUDIO/VIDEO OUT 15 18 36 J401 DC IN 6V EXTERNAL BATTERY DRY BATTERY SIZE “AA” (IEC DESIGNATION LR6) 2PCS‚ 3V DRY BATTERY SIZE “AA” (IEC DESIGNATION LR6) 2PCS‚ 3V RECHARGEABLE BATTRY (NICKEL-CADMIUM) BP-DM10/DM20 2.4V RV301 VOLUME S803 S803 PAL NTSC 11 (11) J301 PHONES/ REMOTE [MAIN BOARD] (SIDE B) 02 OFF ON LIQUID CRYSYAL DISPLAY PLAY MODE ESP RETURN MENU- MENU+ SELECT REPEAT/ ENTER MEGA BASS (page 38) 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 A B C D E F G H I B C E D405 Q413 D422 S D G Q422 T421 1-674-190- 11 (11) 11 (11) Note: • X : parts extracted from the component side. • ® : Through hole. • b : Pattern from the side which enables seeing. (The other layers' patterns are not indicated.) Caution: Pattern face side: Parts on the pattern face side seen from the (Side B) pattern face are indicated. Parts face side: Parts on the parts face side seen from the (Side A) parts face are indicated. w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 27 – – 28 – – 30 – – 29 – – 31 – D-V55 r Refer to page 39 for IC Block Diagrams. r Refer to page 32 for Waveforms. 6-4. SCHEMATIC DIAGRAM (MAIN SECTION) Note: • All capacitors are in µF unless otherwise noted. pF: µµF 50 WV or less are not indicated except for electrolytics and tantalums. • All resistors are in Ω and 1/4 W or less unless otherwise specified. • ¢ : internal component. Note: The components identified by mark ! or dotted line with mark ! are critical for safety. Replace only with part number specified. • A : B+ Line. • Power voltage is dc 6 V and fed with regulated dc power supply from external power voltage jack (J401). • Voltages and waveforms are dc with respect to ground under no-signal conditions. no mark : VIDEO CD PLAY ( ) : AUDIO CD PLAY • Voltages are taken with a VOM (Input impedance 10 MΩ). Voltage variations may be noted due to normal produc- tion tolerances. • Waveforms are taken with a oscilloscope. Voltage variations may be noted due to normal produc- tion tolerances. • Circled numbers refer to waveforms. • Signal path. J : CD L : VIDEO w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 34 – – 35 – – 32 – – 33 – – 36 – D-V55 6-5. SCHEMATIC DIAGRAM (MPEG SECTION) r Refer to page 41 for IC Block Diagram. Note: • All capacitors are in µF unless otherwise noted. pF: µµF 50 WV or less are not indicated except for electrolytics and tantalums. • All resistors are in Ω and 1/4 W or less unless otherwise specified. • A : B+ Line. • Power voltage is dc 6 V and fed with regulated dc power supply from external power voltage jack (J401). • Voltages and waveforms are dc with respect to ground under no-signal conditions. no mark : VIDEO CD PLAY ( ) : AUDIO CD PLAY ∗ : Impossible to measure • Voltages are taken with a VOM (Input impedance 10 MΩ). Voltage variations may be noted due to normal produc- tion tolerances. • Waveforms are taken with a oscilloscope. Voltage variations may be noted due to normal produc- tion tolerances. • Circled numbers refer to waveforms. • Signal path. J : CD L : VIDEO r Waveforms – MAIN Section – 1 IC501 !¶ (RFO) 2 3 4 5 6 VOLT/DIV : 200 mV AC TIME/DIV : 500 ns 0.5 -0.9 Vp-p IC501 !§ (FE) VOLT/DIV : 50 mV AC TIME/DIV : 5 ms IC501 !¢ (TE) VOLT/DIV : 200 mV AC TIME/DIV : 5 ms IC601 @º (VCKI) VOLT/DIV : 0.5 V AC TIME/DIV : 20ns IC601 $∞ (LRCK) VOLT/DIV : 1 V AC TIME/DIV : 5 µs Approx. 120 mVp-p Approx. 500 mVp-p 940 mVp-p 16.9344 MHz 3.5 Vp-p 23.15 µs IC601 $¶ (BCLK) VOLT/DIV : 1 V AC TIME/DIV : 0.1 µs 3.2 Vp-p 483 ns 7 IC601 ^™ (XTAI) 8 9 10 11 12 VOLT/DIV : 0.5 V AC TIME/DIV : 20 ns IC601 ^§ (FSTI) VOLT/DIV : 0.5 V AC TIME/DIV : 50 ns IC681 !∞ (LRCK) VOLT/DIV : 2 V AC TIME/DIV : 10 µs IC681 !¢ (BCLK) VOLT/DIV : 1 V AC TIME/DIV : 200 ns IC681 9 (CLK) VOLT/DIV : 0.5 V AC TIME/DIV : 20 ns IC322 !£ (CKO) VOLT/DIV : 0.2 V AC TIME/DIV : 20 ns 13 IC322 !§ (XTLO) 14 15 16 17 18 VOLT/DIV : 2 V AC TIME/DIV : 20 ns IC322 @£ (BCLK) VOLT/DIV : 1 V AC TIME/DIV : 0.1 µs IC322 @¢ (LRCK) VOLT/DIV : 1 V AC TIME/DIV : 10 µs IC801 *¡ (OSC1) VOLT/DIV : 0.5 V AC TIME/DIV : 100 ns IC502 @¶ (OUT) VOLT/DIV : 1 V AC TIME/DIV : 2 µs IC411 1 (EXT) VOLT/DIV : 2 V AC TIME/DIV : 1 µs 19 IC421 5 (EXT) 20 21 IC802 8 (LX) Q421 C 940 mVp-p 16.9344 MHz 3.3 Vp-p 22.9 µs 3.2 Vp-p 488 ns 940 mVp-p 16.9344 MHz 0.6 Vp-p 16.9344 MHz 3.7 Vp-p 16.9344 MHz 3.2Vp-p 488 ns 3.3 Vp-p 22.9 µs 3.1 Vp-p 11.5 µs 5.9 Vp-p 28 kHz 3.2 Vp-p 180 kHz 4.3 Vp-p 3.8 kHz 3.6 Vp-p 5.78 µsec 1.5 Vp-p 4.19 MHz VOLT/DIV : 1 V AC TIME/DIV : 2 µs VOLT/DIV : 1 V AC TIME/DIV : 0.1 ms VOLT/DIV : 1 V AC TIME/DIV : 2 µs 1.6 Vp-p 91.6 ns r Waveforms – MPEG Section – 1 IC701 (º (TBCK) VOLT/DIV : 1 V AC TIME/DIV : 200 ns 2 IC701 (¡ (ATFS) VOLT/DIV : 1 V AC TIME/DIV : 10 µs 3 IC701 $£ (PCLK2XSCN) VOLT/DIV : 2 V AC TIME/DIV : 1 ms 4 IC721 #¡ (CVOUT) VOLT/DIV : 500 mV AC TIME/DIV : 20 µs 5 IC721 #ª (XO) VOLT/DIV : 2 V AC TIME/DIV : 20 ns 6 IC721 $™ (CK270) VOLT/DIV : 2 V AC TIME/DIV : 20 ns 7 IC723 1 (OUT) VOLT/DIV : 500 mV AC TIME/DIV : 20 µs 3.2 Vp-p 472 ns 3.2 Vp-p 22.7 µs 5.2 Vp-p 27 MHz 1.0 Vp-p H 4.2 Vp-p 27 MHz 3.9 Vp-p 27 MHz 2.0 Vp-p H w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 37 – – 38 – D-V55 6-6. PRINTED WIRING BOARDS (MPEG SECTION) r Semiconductor Location 1 2 3 4 5 6 7 8 9 A B C D E F G 1 2 S D G C456 TP724 C730 TP901 TP910 X720 R723 Q454 TP902 TP711 L451 C715 C729 TP908 IC723 C457 D452 D451 CN901 TP710 TP709 TP744 R455 TP453 TP907 TP904 TP723 TP909 TP722 TP701 TP905 TP705 TP706 TP911 TP906 TP903 TP718 3 2 1 3 2 1 3 2 1 4 5 6 3 4 2 1 11 10 5 22 20 15 34 33 30 25 23 35 44 40 1 12 1 5 10 15 20 22 23 25 30 35 40 44 S D G S D G 1 2 3 4 5 1 10 5 30 35 26 40 45 60 55 70 75 80 76 85 90 95 100 20 25 15 50 51 1 5 10 16 15 32 30 25 20 17 R452 IC721 IC452 TP703 Q453 C710 02 C736 C706 C704 IC702 C713 C455 L724 L702 C738 C709 C734 C724 C714 R722 C728 L721 R704 L725 C705 C725 L722 L723 R721 R460 IC451 C733 C726 C703 R726 C453 C711 C731 TP717 IC722 C722 C721 R458 C454 R457 R725 R724 R459 C735 IC703 C458 R456 C452 C702 Q451 Q452 C460 TAP451 R453 C732 C712 TAP701 R454 C739 C459 C451 R701 IC701 L701 R451 C707 65 11 (11) 1-674-188- 11 (11) 1-674-188- A MAIN BOARD CN601 10 20 24 5 15 23 [MPEG BOARD] (SIDE A) [MPEG BOARD] (SIDE B) (page 23) Note: • X : parts extracted from the component side. • ® : Through hole. • b : Pattern from the side which enables seeing. (The other layers' patterns are not indicated.) Caution: Pattern face side: Parts on the pattern face side seen from the (Side B) pattern face are indicated. Parts face side: Parts on the parts face side seen from the (Side A) parts face are indicated. D451 B-6 D452 B-6 IC451 A-2 IC452 B-4 IC701 D-2 IC702 D-1 IC703 E-3 IC721 C-3 IC722 B-2 IC723 B-6 Q451 C-1 Q452 B-2 Q453 B-2 Q454 B-6 Ref. No. Location w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 39 – – 40 – r IC Block Diagrams (MAIN SECTION) IC322 TC9434AFNEL 21 22 23 24 2 3 5 4 6 7 8 9 10 1 11 12 13 14 15 16 17 18 19 20 DATA INTERFASE CIRCUIT MICRO COMPUTER INTERFASE CIRCUIT OSC TIMING GENERATOR TEST CIRCUIT OUTPUT CIRCUIT OUTPUT CIRCUIT ANALOG FILTER ANALOG FILTER DINAMIC BASS BOOST CIRCUIT DIGITAL FILTER CIRCUIT DEEMPHASIS FILTER CIRCUIT ATTENUATER OPERATIONAL CIRCUIT Σ-∆ MODULATION CIRCUIT LRCK BCLK DATA DBB SDATA SHCK DACLT XVDD XTLO XTLI XGND CKO DVDD TEST SPSL AVDD RO AGND VREF AGND LO AVDD MUTE-0 DGND IC321 TC74VHC157FT SELECT 111 1A 2 3 4 5 6 7 INPUT INPUT OUTPUT OUTPUT 1A 1B 1Y 2A 2B 2Y 1B 1Y 2A 2B 2Y GND 8 VCC STROBE 16 4A 15 14 13 11 12 11 10 INPUT INPUT OUTPUT OUTPUT G 4B 4Y 3A 4A 4B 4Y 3A 3B 9 3B 3Y 3Y S IC361 BA3574BFS MUTE MUTE SW 11 P.SW PW SW 12 IN 1 13 IN 2 14 BIAS OUT 15 BIAS IN 16 RF OUT 17 RF IN 18 BEEP IN 19 VCC 20 RIPPLE FILTER BEEP 10 9 8 BB SW 7 6 5 4 3 2 1 MUTE LP MUTE SW AVC AVC IN AVC DET MIX OUT OUT 1 VREF OUT 2 GND IC501 CXA1791N + – + – APC PD AMP APC LD AMP VREF 1.25V 1 LD 2 PD VC – + RF IV AMP1 3 PD1 VC VC – + RF IV AMP2 4 PD2 VC VC – + RF SUMMING AMP VC – + FOCUS ERROR AMP 18 RFI 19 LDON 20 VCC VCC 17 RFO 16 FE 15 FE BIAS – + F IV AMP 6 F VC VC – + TRACKING ERROR AMP 14 TE VC 5 VEE – + E IV AMP 7 E VC 13 EI 12 EO VC 8 VR VC 10 NC 11 NC VC 9 – + VCC VC BUFFER IC601 CXD2545Q 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80 81 82 92 91 90 89 88 87 86 85 84 83 93 94 95 96 97 98 99 100 SLED PWM GENERATOR TRACKING PWM GENERATOR FOCUS PWM GENERATOR PWM GENERATOR SERVO DSP FOCUS SERVO TRACKING SERVO SLED SERVO CLV PROCESSOR CPU INTERFACE NOISE SHAPER 18-TIMES OVER SAMPLING FILTER CPU INTERFACE CPU INTERFACE ADDRESS GENERATOR CPU INTERFACE PRIORITY ENCODER CPU INTERFACE ERROR CORRECTOR CPU INTERFACE TIMING GENERATOR 2 MIRR DFCT FOK DETECTOR 32K RAM REGISTER D/A DIGITAL PROCESSOR TIMING GENERATOR 1 SYNC PROTECTOR DIGITAL OUT SUBCODE P-W PROCESSOR SUBCODE Q PROCESSOR DIGITAL PLL VARI-PITCH DOUBLE SPEED CPU INTERFACE EFM DEMODULATOR SERIAL PARALLEL PROCESSOR CPU INTERFACE ASYMMETRY CORRECTION 1 2 3 4 5 6 7 8 9 10 11 20 19 18 17 16 15 14 13 12 21 22 23 24 25 46 — 50 61 | 51 PEAK DETECTOR CLOCK GENERATOR MUX     A/D CONVERTER SWITCH & BUFFER SERVO AUTO SEQUENCER SERVO MICRO PROGRAM INTERFACE RFC ADIO AVSS IGEN AVDD VCKI VPCO PDO TES3 TES2 DVSS TEST VCO1 VCO0 SRON SRDR SFON TFDR TRON TRDR TFON FFDR FRON FRDR FFON RFDC TE SE FE VC FILO FILI PCO CLTV AVSS RFAC BIAS ASYI ASYO AVDD ADD ASYE PSSL WDCK LRCK XTAI XTAO XTSL DVSS FSTI FSTO D OUT MD2 C16M C4M SCOR WFCK EMPH SBSO EXCK SQSO SQCK MUTE SENS XRST DIRC SCLK DFSW ATSK DATA XLAT CLOK COUT ADD MIRR DFCT FOK FSW MON MDP MDS LOCK SSTP SFDR 4 3 DA01 | DA11 DA16 | DA12 IC502 MPC17A51VMEL LOW VOLTAGE DETECTOR CHAGE PUMP SAW GEN ERR 1 C2H C1H C1L C2L VCG VIN34 VIN34 OUT 3 A PGND3 OUT 3 B OUT 4 B PGND4 OUT 4 A VIN34 CF4 CLV TED CF3 AGND C11 VR OE SAWTOOTH PSB OUT 1 A OUT 1 B ERR 2 OUT 2 B VR VR OE OE SAWTOOTH SAWTOOTH PSB PSB VR OE SAWTOOTH PSB OUT 2 A OUT 4 B C14 ERR 4 OUT 4 A OUT 3 A OUT 3 B ER R3 C 13 C 12 MOTOR DRIVER CH 1 MOTOR DRIVER CH 2 MOTOR DRIVER CH 3 MOTOR DRIVER CH 4 VLG VG VLG VG VCG VIN12 VLG VG VIN12 VLG VG VIN34 VLG VG VIN34 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 36 35 34 33 32 31 30 29 28 27 26 25 24 23 22 21 20 19 VG DGND CLK OE VCC VIN12 VIN12 OUT 1 A PGND1 OUT 1 B OUT 2 B PGND2 OUT 2 A VIN12 CF2 SLD FED CF1 VC w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 41 – IC721 TC90A07U r IC Block Diagram (MPEG SECTION) 33 34 + + X X 35 36 37 38 39 40 41 42 43 44 1 4 2 5 6 7 8 9 10 11 14 15 16 13 18 19 17 12 22 21 20 3 32 31 30 29 28 27 26 25 24 23 CSYNC HSYNC VSYNC TMS3 VDD CK27I XO GND TMS2 CK270 TMS1 YMS0 MIFH MIFFL MIFFR VBLNKI VDD GND YCDI0 YCDI1 YCDI2 YCDI3 YCDI4 YCDI7 YCDI6 YCDI5 MODE VBLNKO CLPF GND VDD FLD BLK BF AVCC CVOUT AGND COUT AVCC YOUT AGND VREF BIAS1 BIAS2 DAC C Y Cb Cr Y DAC DAC C LEVEL ALIGNMENT C SYNC ADD INTERPO- LATE SYNC GENERATOR INTERPO- LATE ROM LOW-PASS FILTER BURST FLAG BLANKING C SIGNAL GENERRATE LOW-PASS FILTER Y LEVEL ALIGNMENT Cd LEVEL ALIGNMENT YCdCr SEPARATOR CLK GENERATE COLOR BAR GENERATOR www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 42 – SECTION 7 EXPLODED VIEWS NOTE : • -XX, -X mean standardized parts, so they may have some difference from the original one. • Items marked “ * ”are not stocked since they are seldom required for routine service. Some delay should be anticipated when ordering these items. • The mechanical parts with no reference number in the exploded views are not supplied. • Accessories and packing materials are given in the last of this parts list. Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 7-1. CABINET (UPPER) SECTION The components identified by mark ! or dotted line with mark ! are critical for safety. Replace only with part number specified. 1 4-984-847-01 SPRING, TORSION 2 4-984-748-01 KNOB (OPEN) 3 3-318-382-71 SCREW (1.7X4), TAPPING 4 4-984-866-01 COVER, LID 5 1-418-438-11 SWITCH UNIT 6 4-217-534-01 BUTTON (CONTROL) 7 X-4951-142-1 LID SUB ASSY, UPPER 8 X-4951-143-1 CABINET (UPPER) SUB ASSY 9 4-984-849-01 SPRING, TORSION 10 4-984-848-01 BRACKET (SPRING) 11 3-336-395-01 SCREW (B2X10) (G), TAPPING 1 2 3 4 5 6 7 8 9 10 11 not supplied www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 43 – Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 7-2. CABINET (LOWER) SECTION 51 4-962-025-21 FOOT, RUBBER 52 X-4951-144-1 CABINET (LOWER) SUB ASSY 53 4-984-747-01 KNOB (H-R) 54 A-3321-971-A MAIN BOARD, COMPLETE 55 A-3321-973-A MPEG BOARD, COMPLETE 56 4-993-138-01 INSULATOR 57 4-978-696-01 TERMINAL BOARD (RELAY), BATTERY 58 4-984-750-11 LID, BATTERY CASE * 59 1-674-189-11 IR BOARD 60 1-793-139-11 LEAD (WITH CONNECTOR) 61 4-978-695-01 PLATE, TERMINAL, BATTERY 62 4-984-850-01 TERMINAL BOARD (BATTERY CASE) 63 4-984-851-01 TERMINAL BOARD, BATTERY 51 52 53 53 54 55 56 56 57 58 59 60 61 62 63 CDM-2901ABA www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 44 – 101 A-3320-684-A SCREW ASSY, FEED 102 3-318-203-11 SCREW (B1.7), TAPPING 103 4-972-163-04 SPRING, SLED 104 1-783-093-11 LEAD (WITH CONNECTOR) 105 7-627-850-17 SCREW,PRECISION +P 1.4X2.5 106 3-719-401-11 SCREW (B1.7), TAPPING * 107 4-984-320-01 CHASSIS 108 4-974-003-01 GEAR (B) Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 109 1-667-512-11 SLIDE FLEXIBLE BOARD !110 X-4950-060-1 OPTICAL PICK-UP (DAX-01A2 RP) 111 4-972-165-01 RACK 112 4-973-631-01 SCREW M901 A-3328-115-A MOTOR ASSY, SLED (SLED) (INCLUDING GEAR) M902 A-3328-114-A MOTOR ASSY, TURN TABLE (SPINDLE) S901 1-571-099-21 SWITCH (1 KEY) (LIMIT) The components identified by mark ! or dotted line with mark ! are critical for safety. Replace only with part number specified. 7-3. OPTICAL PICK-UP SECTION (CDM-2901ABA) M902 M901 S901 101 102 103 104 105 106 107 108 109 110 111 112 not supplied www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 45 – NOTE : • Due to standardization, replacements in the parts list may be different from the parts specified in the diagrams or the components used on the set. • -XX, -X mean standardized parts, so they may have some difference from the original one. • RESISTORS All resistors are in ohms METAL : Metal-film resistor METAL OXIDE :Metal oxide-film resistor F : nonflammable • Items marked “ * ”are not stocked since they are seldom required for routine service. Some delay should be anticipated when ordering these items. • SEMICONDUCTORS In each case, u : µ , for example : uA.... : µ A.... , uPA.... : µ PA.... uPB.... : µ PB.... , uPC.... : µ PC.... uPD.... : µ PD.... • CAPACITORS uF : µ F • COILS uH : µ H When indicating parts by reference num- ber, please include the board. The components identified by mark ! or dotted line with mark ! are critical for safety. Replace only with part number specified. SECTION 8 ELECTRICAL PARTS LIST Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark * 1-674-189-11 IR BOARD ******** 1-793-139-11 LEAD (WITH CONNECTOR) < CAPACITOR > C1 1-104-851-11 TANTAL. CHIP 10uF 20% 10V < IC > IC1 8-749-015-96 IC GP1UC10J ************************************************************** A-3321-971-A MAIN BOARD, COMPLETE ********************* 4-978-695-01 PLATE, TERMINAL, BATTERY 4-984-850-01 TERMINAL BOARD (BATTERY CASE) 4-984-851-01 TERMINAL BOARD, BATTERY < CAPACITOR > C101 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C102 1-107-686-11 TANTAL. CHIP 4.7uF 20% 16V C103 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C104 1-109-982-11 CERAMIC CHIP 1uF 10% 10V C105 1-162-927-11 CERAMIC CHIP 100PF 5% 50V C106 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V C201 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C202 1-107-686-11 TANTAL. CHIP 4.7uF 20% 16V C203 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C204 1-109-982-11 CERAMIC CHIP 1uF 10% 10V C205 1-162-927-11 CERAMIC CHIP 100PF 5% 50V C206 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V C321 1-115-156-11 CERAMIC CHIP 1uF 10V C323 1-115-156-11 CERAMIC CHIP 1uF 10V C324 1-162-921-11 CERAMIC CHIP 33PF 5% 50V C325 1-109-982-11 CERAMIC CHIP 1uF 10% 10V C327 1-115-156-11 CERAMIC CHIP 1uF 10V C328 1-126-209-11 ELECT CHIP 100uF 20% 4V C329 1-109-982-11 CERAMIC CHIP 1uF 10% 10V C330 1-126-246-11 ELECT CHIP 220uF 20% 4V C351 1-164-156-11 CERAMIC CHIP 0.1uF 25V C352 1-109-982-11 CERAMIC CHIP 1uF 10% 10V C353 1-104-851-11 TANTAL. CHIP 10uF 20% 10V C361 1-164-156-11 CERAMIC CHIP 0.1uF 25V C362 1-104-847-11 TANTAL. CHIP 22uF 20% 4V C364 1-124-779-00 ELECT CHIP 10uF 20% 16V C365 1-115-156-11 CERAMIC CHIP 1uF 10V C366 1-126-395-11 ELECT 22uF 20% 16V C367 1-115-156-11 CERAMIC CHIP 1uF 10V C368 1-164-156-11 CERAMIC CHIP 0.1uF 25V C369 1-164-677-11 CERAMIC CHIP 0.033uF 10% 16V C370 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V C371 1-115-156-11 CERAMIC CHIP 1uF 10V C372 1-115-156-11 CERAMIC CHIP 1uF 10V C375 1-115-565-11 CERAMIC CHIP 2.2uF 10% 10V C401 1-109-982-11 CERAMIC CHIP 1uF 10% 10V C411 1-164-156-11 CERAMIC CHIP 0.1uF 25V C412 1-115-416-11 CERAMIC CHIP 1000PF 5% 25V C413 1-164-156-11 CERAMIC CHIP 0.1uF 25V C414 1-119-764-11 ELECT 47uF 20% 4V C415 1-115-156-11 CERAMIC CHIP 1uF 10V C416 1-115-156-11 CERAMIC CHIP 1uF 10V C417 1-128-416-11 ELECT CHIP 100uF 20% 16V C418 1-119-764-11 ELECT 47uF 20% 4V C421 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V C422 1-164-156-11 CERAMIC CHIP 0.1uF 25V C423 1-119-764-11 ELECT 47uF 20% 4V C424 1-115-156-11 CERAMIC CHIP 1uF 10V C425 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V C426 1-115-156-11 CERAMIC CHIP 1uF 10V C427 1-128-414-21 ELECT CHIP 220uF 20% 6.3V C428 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V C429 1-164-315-11 CERAMIC CHIP 470PF 5% 50V C430 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V C501 1-164-156-11 CERAMIC CHIP 0.1uF 25V C502 1-164-156-11 CERAMIC CHIP 0.1uF 25V C503 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V C504 1-115-156-11 CERAMIC CHIP 1uF 10V C505 1-104-852-11 TANTAL. CHIP 22uF 20% 10V C506 1-164-156-11 CERAMIC CHIP 0.1uF 25V C507 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V C508 1-104-851-11 TANTAL. CHIP 10uF 20% 10V MAIN IR www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 46 – C509 1-110-569-11 TANTAL. CHIP 47uF 20% 6.3V C510 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V C511 1-110-569-11 TANTAL. CHIP 47uF 20% 6.3V C512 1-162-957-11 CERAMIC CHIP 220PF 5% 50V C513 1-162-957-11 CERAMIC CHIP 220PF 5% 50V C514 1-162-927-11 CERAMIC CHIP 100PF 5% 50V C515 1-162-957-11 CERAMIC CHIP 220PF 5% 50V C516 1-162-922-11 CERAMIC CHIP 39PF 5% 50V C517 1-104-852-11 TANTAL. CHIP 22uF 20% 10V C518 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V C519 1-162-922-11 CERAMIC CHIP 39PF 5% 50V C520 1-115-156-11 CERAMIC CHIP 1uF 10V C521 1-115-156-11 CERAMIC CHIP 1uF 10V C522 1-110-563-11 CERAMIC CHIP 0.068uF 10% 16V C523 1-104-851-11 TANTAL. CHIP 10uF 20% 10V C525 1-164-217-11 CERAMIC CHIP 150PF 5% 50V C526 1-164-217-11 CERAMIC CHIP 150PF 5% 50V C527 1-164-217-11 CERAMIC CHIP 150PF 5% 50V C528 1-164-217-11 CERAMIC CHIP 150PF 5% 50V C529 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C530 1-164-677-11 CERAMIC CHIP 0.033uF 10% 16V C532 1-164-966-11 CERAMIC CHIP 0.0022uF 10% 50V C533 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V C534 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V C535 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C536 1-115-156-11 CERAMIC CHIP 1uF 10V C601 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C602 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C603 1-164-156-11 CERAMIC CHIP 0.1uF 25V C604 1-164-156-11 CERAMIC CHIP 0.1uF 25V C605 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C606 1-164-315-11 CERAMIC CHIP 470PF 5% 50V C607 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V C608 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V C609 1-162-927-11 CERAMIC CHIP 100PF 5% 50V C611 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V C612 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V C613 1-104-852-11 TANTAL. CHIP 22uF 20% 10V C615 1-162-965-11 CERAMIC CHIP 0.0015uF 10% 50V C616 1-164-156-11 CERAMIC CHIP 0.1uF 25V C617 1-104-852-11 TANTAL. CHIP 22uF 20% 10V C618 1-164-156-11 CERAMIC CHIP 0.1uF 25V C619 1-104-851-11 TANTAL. CHIP 10uF 20% 10V C682 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C683 1-104-851-11 TANTAL. CHIP 10uF 20% 10V C684 1-115-156-11 CERAMIC CHIP 1uF 10V C685 1-115-156-11 CERAMIC CHIP 1uF 10V C751 1-162-919-11 CERAMIC CHIP 22PF 5% 50V C752 1-119-944-11 ELECT 470uF 20% 4V C801 1-104-851-11 TANTAL. CHIP 10uF 20% 10V C802 1-115-156-11 CERAMIC CHIP 1uF 10V C803 1-104-852-11 TANTAL. CHIP 22uF 20% 10V C804 1-109-982-11 CERAMIC CHIP 1uF 10% 10V C805 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C806 1-104-852-11 TANTAL. CHIP 22uF 20% 10V C807 1-104-851-11 TANTAL. CHIP 10uF 20% 10V C808 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C809 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C810 1-164-156-11 CERAMIC CHIP 0.1uF 25V C811 1-164-156-11 CERAMIC CHIP 0.1uF 25V C812 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C816 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V < CONNECTOR > CN501 1-779-761-21 CONNECTOR, FPC (ZIF) 14P CN502 1-784-342-21 HOUSING, CONNECTOR 2P CN503 1-784-342-31 HOUSING, CONNECTOR 2P CN504 1-784-342-11 HOUSING, CONNECTOR 2P CN601 1-766-295-31 CONNECTOR, BOARD TO BOARD 24P CN801 1-766-492-21 CONNECTOR, FFC/FPC (ZIF) 24P * CN802 1-793-137-21 PIN, CONNECTOR 3P < DIODE > D101 8-719-039-99 DIODE UMZ8.2T D102 8-719-039-99 DIODE UMZ8.2T D201 8-719-039-99 DIODE UMZ8.2T D202 8-719-039-99 DIODE UMZ8.2T D301 8-719-039-99 DIODE UMZ8.2T D302 8-719-039-99 DIODE UMZ8.2T D351 8-719-049-09 DIODE 1SS367-T3SONY D361 8-719-404-35 DIODE MA141WK D401 8-719-048-98 DIODE RB160L-40TE25 D402 8-719-073-92 DIODE RB060L-40TE25 D404 8-719-073-92 DIODE RB060L-40TE25 D405 8-719-073-01 DIODE MA111-TX D411 8-719-073-92 DIODE RB060L-40TE25 D412 8-719-073-92 DIODE RB060L-40TE25 D421 8-719-049-09 DIODE 1SS367-T3SONY D422 8-719-977-20 DIODE DTZ8.2B D501 8-719-404-50 DIODE MA111-TX D601 8-719-024-81 DIODE 1SS300-TE85L D681 8-719-049-09 DIODE 1SS367-T3SONY D682 8-719-049-09 DIODE 1SS367-T3SONY D801 8-719-049-09 DIODE 1SS367-T3SONY < FERRITE BEAD > FB101 1-500-444-11 FERRITE FB102 1-500-444-11 FERRITE FB201 1-500-444-11 FERRITE FB202 1-500-444-11 FERRITE FB301 1-500-444-11 FERRITE FB321 1-414-656-11 FERRITE FB681 1-414-656-11 FERRITE FB682 1-414-656-11 FERRITE FB683 1-414-656-11 FERRITE FB751 1-414-656-11 FERRITE FB801 1-414-656-11 FERRITE FB802 1-500-444-11 FERRITE FB803 1-500-444-11 FERRITE FB804 1-500-444-11 FERRITE FB805 1-500-444-11 FERRITE FB806 1-500-444-11 FERRITE FB807 1-500-444-11 FERRITE FB808 1-500-444-11 FERRITE MAIN Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 47 – < IC > IC321 8-759-524-10 IC TC74VHC157FT(EL) IC322 8-759-459-18 IC TC9434AFNEL IC361 8-759-386-50 IC BA3574BFS IC411 8-759-578-53 IC XC6365D103MR IC421 8-759-565-69 IC XC6367B102MR IC501 8-752-069-29 IC CXA1791N IC502 8-759-483-62 IC MPC17A51VMEL IC503 8-759-293-74 IC NJM2100E IC504 8-759-293-74 IC NJM2100E IC601 8-752-369-78 IC CXD2545Q IC602 8-759-548-99 IC SN74LV08APWR IC681 8-759-580-87 IC RL5C358B IC682 8-759-498-44 IC MSM51V4400D-70TSK IC801 8-759-638-08 IC MSM65354-418GS-BK4 IC802 8-759-176-73 IC RS5RJ32271-T1 < JACK > J301 1-580-680-11 JACK (PHONES/REMOTE) J401 1-691-099-51 JACK,DC(POLARITY UNIFIED TYPE) (DC IN 6V) J901 1-778-633-21 JACK (AUDIO/VIDEO OUT) < COIL > L321 1-412-979-21 INDUCTOR 1uH L322 1-412-002-31 INDUCTOR CHIP 4.7uH L323 1-412-002-31 INDUCTOR CHIP 4.7uH L324 1-412-002-31 INDUCTOR CHIP 4.7uH L401 1-414-392-21 INDUCTOR 1uH L402 1-414-392-21 INDUCTOR 1uH L411 1-469-437-21 INDUCTOR 22uH L501 1-414-404-11 INDUCTOR 100uH L502 1-414-404-11 INDUCTOR 100uH L503 1-414-398-11 INDUCTOR 10uH L504 1-414-402-11 INDUCTOR 47uH L505 1-414-402-11 INDUCTOR 47uH L506 1-414-398-11 INDUCTOR 10uH L601 1-410-997-42 INDUCTOR CHIP 2.2uH L602 1-410-997-42 INDUCTOR CHIP 2.2uH L801 1-414-434-11 INDUCTOR 100uH < TRANSISTOR > Q101 8-729-231-74 TRANSISTOR 2SC4116-GL Q201 8-729-231-74 TRANSISTOR 2SC4116-GL Q351 8-729-231-74 TRANSISTOR 2SC4116-GL Q352 8-729-903-10 TRANSISTOR FMW1 Q353 8-729-904-86 TRANSISTOR 2SB1197K-Q Q361 8-729-907-39 TRANSISTOR IMD2 Q362 8-729-231-74 TRANSISTOR 2SC4116-GL Q363 8-729-029-14 TRANSISTOR DTC144EUA-T106 Q412 8-729-047-90 TRANSISTOR XP162A11C0PR Q413 8-729-029-14 TRANSISTOR DTC144EUA-T106 Q421 8-729-028-61 TRANSISTOR 2SD1950VKVLVM Q422 8-729-048-59 TRANSISTOR XP161A1265PR Q501 8-729-904-86 TRANSISTOR 2SB1197K-Q Q502 8-729-930-32 TRANSISTOR UMH11-TN Q503 8-729-930-32 TRANSISTOR UMH11-TN Q504 8-729-029-14 TRANSISTOR DTC144EUA-T106 Q505 8-729-029-14 TRANSISTOR DTC144EUA-T106 Q506 8-729-028-91 TRANSISTOR DTA144EUA-T106 Q507 8-729-231-74 TRANSISTOR 2SC4116-GL Q601 8-729-029-14 TRANSISTOR DTC144EUA-T106 Q801 8-729-028-91 TRANSISTOR DTA144EUA-T106 Q802 8-729-231-74 TRANSISTOR 2SC4116-GL Q812 8-729-231-74 TRANSISTOR 2SC4116-GL < RESISTOR > R101 1-216-813-11 RES,CHIP 220 5% 1/16W R102 1-216-821-11 RES,CHIP 1K 5% 1/16W R103 1-216-833-91 RES,CHIP 10K 5% 1/16W R104 1-216-821-11 RES,CHIP 1K 5% 1/16W R105 1-216-845-11 RES,CHIP 100K 5% 1/16W R106 1-216-825-11 RES,CHIP 2.2K 5% 1/16W R107 1-216-789-11 RES,CHIP 2.2 5% 1/16W R201 1-216-813-11 RES,CHIP 220 5% 1/16W R202 1-216-821-11 RES,CHIP 1K 5% 1/16W R203 1-216-833-91 RES,CHIP 10K 5% 1/16W R204 1-216-821-11 RES,CHIP 1K 5% 1/16W R205 1-216-845-11 RES,CHIP 100K 5% 1/16W R206 1-216-825-11 RES,CHIP 2.2K 5% 1/16W R207 1-216-789-11 RES,CHIP 2.2 5% 1/16W R321 1-216-823-11 RES,CHIP 1.5K 5% 1/16W R322 1-216-857-11 RES,CHIP 1M 5% 1/16W R323 1-216-803-11 RES,CHIP 33 5% 1/16W R351 1-216-833-91 RES,CHIP 10K 5% 1/16W R352 1-216-847-11 RES,CHIP 150K 5% 1/16W R353 1-216-821-11 RES,CHIP 1K 5% 1/16W R354 1-216-817-11 RES,CHIP 470 5% 1/16W R362 1-216-845-11 RES,CHIP 100K 5% 1/16W R363 1-216-857-11 RES,CHIP 1M 5% 1/16W R364 1-216-837-11 RES,CHIP 22K 5% 1/16W R365 1-216-821-11 RES,CHIP 1K 5% 1/16W R401 1-218-887-11 METAL CHIP 47K 0.50% 1/16W R402 1-218-903-11 METAL CHIP 220K 0.50% 1/16W R403 1-218-891-11 METAL CHIP 68K 0.50% 1/16W R404 1-218-879-11 METAL CHIP 22K 0.50% 1/16W R413 1-216-849-11 RES,CHIP 220K 5% 1/16W R414 1-218-891-11 METAL CHIP 68K 0.50% 1/16W R415 1-218-883-11 METAL CHIP 33K 0.50% 1/16W R416 1-216-857-11 RES,CHIP 1M 5% 1/16W R417 1-216-809-11 RES,CHIP 100 5% 1/16W R418 1-216-825-11 RES,CHIP 2.2K 5% 1/16W R421 1-216-849-11 RES,CHIP 220K 5% 1/16W R422 1-218-883-11 METAL CHIP 33K 0.50% 1/16W R423 1-218-875-11 METAL CHIP 15K 0.50% 1/16W R424 1-216-857-11 RES, CHIP 1M 5% 1/16W R425 1-216-815-11 RES, CHIP 330 5% 1/16W R426 1-216-797-11 RES, CHIP 10 5% 1/16W R427 1-216-809-11 RES, CHIP 100 5% 1/16W R428 1-216-821-11 RES, CHIP 1K 5% 1/16W R429 1-216-797-11 RES, CHIP 10 5% 1/16W R501 1-216-845-11 RES, CHIP 100K 5% 1/16W R502 1-216-845-11 RES, CHIP 100K 5% 1/16W R503 1-216-845-11 RES, CHIP 100K 5% 1/16W MAIN Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 48 – R504 1-216-845-11 RES, CHIP 100K 5% 1/16W R505 1-216-850-11 RES, CHIP 270K 5% 1/16W R506 1-216-850-11 RES, CHIP 270K 5% 1/16W R507 1-216-821-11 RES, CHIP 1K 5% 1/16W R508 1-216-845-11 RES, CHIP 100K 5% 1/16W R509 1-216-833-91 RES,CHIP 10K 5% 1/16W R510 1-216-308-00 RES, CHIP 4.7 5% 1/10W R511 1-216-843-11 RES, CHIP 68K 5% 1/16W R512 1-216-835-11 RES, CHIP 15K 5% 1/16W R513 1-216-833-91 RES,CHIP 10K 5% 1/16W R514 1-216-824-11 RES, CHIP 1.8K 5% 1/16W R515 1-216-837-11 RES, CHIP 22K 5% 1/16W R516 1-216-821-11 RES, CHIP 1K 5% 1/16W R517 1-216-821-11 RES, CHIP 1K 5% 1/16W R518 1-216-841-11 RES, CHIP 47K 5% 1/16W R519 1-216-836-11 RES, CHIP 18K 5% 1/16W R520 1-216-823-11 RES, CHIP 1.5K 5% 1/16W R521 1-216-837-11 RES, CHIP 22K 5% 1/16W R522 1-216-864-11 RES, CHIP 0 5% 1/16W R523 1-216-824-11 RES, CHIP 1.8K 5% 1/16W R524 1-216-857-11 RES, CHIP 1M 5% 1/16W R525 1-216-835-11 RES, CHIP 15K 5% 1/16W R526 1-216-845-11 RES, CHIP 100K 5% 1/16W R527 1-216-849-11 RES, CHIP 220K 5% 1/16W R528 1-216-864-11 RES, CHIP 0 5% 1/16W R529 1-216-843-11 RES, CHIP 68K 5% 1/16W R530 1-216-845-11 RES, CHIP 100K 5% 1/16W R531 1-216-825-11 RES, CHIP 2.2K 5% 1/16W R532 1-216-825-11 RES, CHIP 2.2K 5% 1/16W R534 1-216-845-11 RES, CHIP 100K 5% 1/16W R535 1-216-845-11 RES, CHIP 100K 5% 1/16W R536 1-216-845-11 RES, CHIP 100K 5% 1/16W R537 1-216-845-11 RES, CHIP 100K 5% 1/16W R538 1-216-845-11 RES, CHIP 100K 5% 1/16W R539 1-216-845-11 RES, CHIP 100K 5% 1/16W R540 1-216-845-11 RES, CHIP 100K 5% 1/16W R541 1-216-845-11 RES, CHIP 100K 5% 1/16W R542 1-216-821-11 RES, CHIP 1K 5% 1/16W R543 1-216-845-11 RES, CHIP 100K 5% 1/16W R544 1-216-861-11 RES, CHIP 2.2M 5% 1/16W R545 1-216-843-11 RES, CHIP 68K 5% 1/16W R546 1-216-845-11 RES, CHIP 100K 5% 1/16W R547 1-216-845-11 RES, CHIP 100K 5% 1/16W R548 1-216-845-11 RES, CHIP 100K 5% 1/16W R549 1-216-845-11 RES, CHIP 100K 5% 1/16W R550 1-216-845-11 RES, CHIP 100K 5% 1/16W R551 1-216-845-11 RES, CHIP 100K 5% 1/16W R553 1-216-809-11 RES, CHIP 100 5% 1/16W R554 1-216-829-11 RES, CHIP 4.7K 5% 1/16W R555 1-216-825-11 RES, CHIP 2.2K 5% 1/16W R556 1-216-825-11 RES, CHIP 2.2K 5% 1/16W R557 1-216-837-11 RES, CHIP 22K 5% 1/16W R558 1-216-864-11 RES, CHIP 0 5% 1/16W R601 1-216-833-91 RES,CHIP 10K 5% 1/16W R602 1-216-833-91 RES,CHIP 10K 5% 1/16W R603 1-216-841-11 RES, CHIP 47K 5% 1/16W R604 1-216-845-11 RES, CHIP 100K 5% 1/16W R605 1-216-839-11 RES, CHIP 33K 5% 1/16W R606 1-216-831-11 RES, CHIP 6.8K 5% 1/16W R607 1-216-833-91 RES,CHIP 10K 5% 1/16W R608 1-216-857-11 RES, CHIP 1M 5% 1/16W R609 1-216-827-11 RES, CHIP 3.3K 5% 1/16W R610 1-216-827-11 RES, CHIP 3.3K 5% 1/16W R611 1-216-827-11 RES, CHIP 3.3K 5% 1/16W R612 1-216-829-11 RES, CHIP 4.7K 5% 1/16W R613 1-216-827-11 RES, CHIP 3.3K 5% 1/16W R614 1-216-827-11 RES, CHIP 3.3K 5% 1/16W R615 1-216-825-11 RES, CHIP 2.2K 5% 1/16W R616 1-216-827-11 RES, CHIP 3.3K 5% 1/16W R617 1-216-827-11 RES, CHIP 3.3K 5% 1/16W R618 1-216-825-11 RES, CHIP 2.2K 5% 1/16W R619 1-216-827-11 RES, CHIP 3.3K 5% 1/16W R620 1-216-864-11 RES, CHIP 0 5% 1/16W R621 1-216-829-11 RES, CHIP 4.7K 5% 1/16W R681 1-216-833-91 RES,CHIP 10K 5% 1/16W R752 1-216-833-91 RES,CHIP 10K 5% 1/16W R753 1-216-811-11 RES, CHIP 150 5% 1/16W R754 1-216-811-11 RES, CHIP 150 5% 1/16W R801 1-216-845-11 RES, CHIP 100K 5% 1/16W R802 1-216-845-11 RES, CHIP 100K 5% 1/16W R803 1-216-845-11 RES, CHIP 100K 5% 1/16W R804 1-216-851-11 RES, CHIP 330K 5% 1/16W R805 1-216-813-11 RES, CHIP 220 5% 1/16W R806 1-216-813-11 RES, CHIP 220 5% 1/16W R807 1-216-853-11 RES, CHIP 470K 5% 1/16W R809 1-216-857-11 RES, CHIP 1M 5% 1/16W R810 1-216-845-11 RES, CHIP 100K 5% 1/16W R811 1-216-853-11 RES, CHIP 470K 5% 1/16W R812 1-216-833-91 RES,CHIP 10K 5% 1/16W R813 1-216-853-11 RES, CHIP 470K 5% 1/16W R814 1-216-853-11 RES, CHIP 470K 5% 1/16W R815 1-216-813-11 RES, CHIP 220 5% 1/16W R816 1-216-813-11 RES, CHIP 220 5% 1/16W R817 1-216-857-11 RES, CHIP 1M 5% 1/16W R818 1-216-821-11 RES, CHIP 1K 5% 1/16W R819 1-216-833-91 RES,CHIP 10K 5% 1/16W R820 1-216-853-11 RES, CHIP 470K 5% 1/16W R821 1-216-861-11 RES, CHIP 2.2M 5% 1/16W R822 1-216-855-11 RES, CHIP 680K 5% 1/16W R823 1-216-853-11 RES, CHIP 470K 5% 1/16W R824 1-216-841-11 RES, CHIP 47K 5% 1/16W R825 1-216-853-11 RES, CHIP 470K 5% 1/16W R826 1-216-833-91 RES,CHIP 10K 5% 1/16W < VARIABLE RESISTOR > RV301 1-223-382-11 RES, VAR, CARBON 10K/10K (∑ VOLUME) < SWITCH > S801 1-572-922-11 SWITCH, SLIDE (RESUME) S802 1-572-922-11 SWITCH, SLIDE (HOLD c) S803 1-572-922-11 SWITCH, SLIDE (PAL/NTSC) S804 1-570-953-11 SWITCH, PUSH (1 KEY) (DOOR OPEN/CLOSE) < RANSFORMER > T421 1-433-891-21 TRANSFORMER, DC-DC CONVERTER MAIN Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 49 – < VIBRATOR > X321 1-767-366-21 VIBRATOR, CERAMIC (16.934MHz) X801 1-579-063-41 VIBRATOR, CERAMIC (4.19MHz) ************************************************************** A-3321-973-A MPEG BOARD, COMPLETE ********************* < CAPACITOR > C451 1-104-851-11 TANTAL. CHIP 10uF 20% 10V C451 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V C452 1-127-739-11 TANTALUM 22uF 10V C453 1-115-156-11 CERAMIC CHIP 1uF 10V C454 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V C455 1-115-156-11 CERAMIC CHIP 1uF 10V C456 1-119-765-11 ELECT 47uF 20% 6.3V C457 1-164-156-11 CERAMIC CHIP 0.1uF 25V C458 1-115-416-11 CERAMIC CHIP 1000PF 5% 25V C460 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V C702 1-127-739-11 TANTALUM 22uF 10V C703 1-115-156-11 CERAMIC CHIP 1uF 10V C704 1-104-851-11 TANTAL. CHIP 10uF 20% 10V C705 1-104-851-11 TANTAL. CHIP 10uF 20% 10V C706 1-115-156-11 CERAMIC CHIP 1uF 10V C707 1-104-851-11 TANTAL. CHIP 10uF 20% 10V C709 1-164-156-11 CERAMIC CHIP 0.1uF 25V C710 1-164-156-11 CERAMIC CHIP 0.1uF 25V C711 1-127-739-11 TANTALUM 22uF 10V C712 1-164-156-11 CERAMIC CHIP 0.1uF 25V C713 1-127-739-11 TANTALUM 22uF 10V C714 1-115-156-11 CERAMIC CHIP 1uF 10V C715 1-119-944-11 ELECT 470uF 20% 4V C721 1-164-156-11 CERAMIC CHIP 0.1uF 25V C722 1-164-156-11 CERAMIC CHIP 0.1uF 25V C724 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C725 1-164-156-11 CERAMIC CHIP 0.1uF 25V C726 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C727 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C728 1-127-739-11 TANTALUM 22uF 10V C729 1-162-927-11 CERAMIC CHIP 100PF 5% 50V C730 1-127-739-11 TANTALUM 22uF 10V C731 1-115-156-11 CERAMIC CHIP 1uF 10V C732 1-164-156-11 CERAMIC CHIP 0.1uF 25V C733 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V C734 1-162-911-11 CERAMIC CHIP 6PF 0.5PF 50V C735 1-162-923-11 CERAMIC CHIP 47PF 5% 50V C736 1-162-923-11 CERAMIC CHIP 47PF 5% 50V C738 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C739 1-127-739-11 TANTALUM 22uF 10V < CONNECTOR > CN901 1-778-710-41 CONNECTOR, BOARD TO BOARD 24P < DIODE > D451 8-719-048-98 DIODE RB160L-40TE25 D452 8-719-049-09 DIODE 1SS367-T3SONY < IC > IC451 8-759-586-58 IC XC6367B103MR IC452 8-759-530-69 IC XC61AC4502PR IC701 8-759-493-57 IC ES3210 IC702 8-759-638-33 IC MX23C1010TI-90-SG5 IC703 8-759-498-43 IC MSM54V16258ASL-45TSK IC721 8-759-493-55 IC TC90A07U IC722 8-759-085-76 IC S-81332HG-KC-T1 IC723 8-759-433-44 IC MM1031XML < COIL > L451 1-414-433-11 INDUCTOR 47uH L701 1-410-997-42 INDUCTOR CHIP 2.2uH L702 1-414-392-21 INDUCTOR 1uH L721 1-410-993-42 INDUCTOR CHIP 1uH L722 1-412-002-31 INDUCTOR CHIP 4.7uH L723 1-414-398-11 INDUCTOR 10uH L724 1-412-979-21 INDUCTOR 1uH L725 1-410-997-42 INDUCTOR 2.2uH < TRANSISTOR > Q451 8-729-047-90 TRANSISTOR XP162A11C0PR Q452 8-729-047-90 TRANSISTOR XP162A11C0PR Q453 8-729-930-32 TRANSISTOR UMH11 Q454 8-729-048-59 TRANSISTOR XP161A1265PR < RESISTOR > R451 1-216-857-11 RES,CHIP 1M 5% 1/16W R452 1-216-857-11 RES,CHIP 1M 5% 1/16W R453 1-216-833-91 RES,CHIP 10K 5% 1/16W R454 1-216-809-11 RES,CHIP 100 5% 1/16W R455 1-216-857-11 RES,CHIP 1M 5% 1/16W R456 1-218-883-11 METAL, CHIP 33K 0.50% 1/16W R457 1-218-871-11 METAL, CHIP 10K 0.50% 1/16W R458 1-216-841-11 RES,CHIP 47K 5% 1/16W R459 1-216-813-11 RES,CHIP 220 5% 1/16W R460 1-216-296-11 RES,CHIP 0 5% 1/16W R701 1-216-833-91 RES,CHIP 10K 5% 1/16W R704 1-216-845-11 RES,CHIP 100K 5% 1/16W R721 1-218-887-11 METAL, CHIP 47K 0.50% 1/16W R722 1-218-883-11 METAL, CHIP 33K 0.50% 1/16W R723 1-216-809-11 RES,CHIP 100 5% 1/16W R724 1-216-857-11 RES,CHIP 1M 5% 1/16W R725 1-216-845-11 RES,CHIP 100K 5% 1/16W R726 1-216-845-11 RES,CHIP 100K 5% 1/16W < VIBRATOR > X720 1-767-519-11 VIBRATOR, CRYSTAL (27MHz) ************************************************************** MISCELLANEOUS ************** 5 1-418-438-11 SWITCH UNIT 60 1-793-139-11 LEAD (WITH CONNECTOR) 104 1-783-093-11 LEAD (WITH CONNECTOR) 109 1-667-512-11 SLIDE FLEXIBLE BOARD !110 X-4950-060-1 OPTICAL PICK-UP (DAX-01A2 RP) MPEG Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark The components identified by mark ! or dotted line with mark ! are critical for safety. Replace only with part number specified. MAIN www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com – 50 – M901 A-3328-115-A MOTOR ASSY, SLED (SLED) (INCLUDING GEAR) M902 A-3328-114-A MOTOR ASSY, TURN TABLE (SPINDLE) S901 1-571-099-21 SWITCH (1 KEY) (LIMIT) ************************************************************** ACCESSORIES & PACKING MATERIALS ******************************* ! 1-467-511-41 ADAPTOR, AC (AC-MZ60) (E) 1-418-600-11 REMOTE CONTROL UNIT (RM-DM29) ! 1-475-712-11 ADAPTOR, AC (AC-E67A) (Chinese) ! 1-475-754-11 ADAPTOR, AC (AC-E67) (Hong kong) 1-759-042-21 BATTERY CASE 1-783-028-11 CORD, CONNECTION 3-866-599-11 MANUAL, INSTRUCTION (ENGLISH, TRADITIONAL CHINESE) (E,Hong kong) 3-866-599-21 MANUAL, INSTRUCTION (ENGLISH, SIMPLIFIED CHINESE) (Chinese) 8-917-658-90 REMOTE COMMANDER RMT-DV10 8-953-304-90 RECEIVER MDR-E805SP SET 4-991-047-01 LID, BATTERY CASE (FOR RMT-DV10) Ref. No. Part No. Description Remark The components identified by mark ! or dotted line with mark ! are critical for safety. Replace only with part number specified. D-V55 9-926-996-11 Sony Corporation Personal Audio Company 99E027025-1 Printed in Singapore © 1999.5 Published by General Engineering Dept. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com
