FM/AM PORTABLE CD PLAYER Canadian Model AEP Model D-NF007 E Model D-NF007/NF0070 Australian Model D-NF007 SPECIFICATIONS D-NF007/NF0070 Ver. 1.1 2005.11 Model Name Using Similar Mechanism D-FJ003 CD Mechanism Type CDM-3525A Optical Pick-up Name DAX-25E 9-879-827-02 2005K02-1 © 2005.11 Sony Corporation Personal Audio Division Published by Sony Engineering Corporation SERVICE MANUAL CD player System: Compact disc digital audio system Laser diode properties: Emission duration: Continuous Laser output: Less than 44.6 µW (This output is the value measured at a distance of 200 mm from the objective lens surface on the optical pick-up block with 7 mm aperture.) Radio Frequency range • Canadian and Latin American models 9 kHz step: FM: 87.5 - 108 MHz AM: 531 - 1 710 kHz 10 kHz step: FM: 87.5 - 108 MHz AM: 530 - 1 710 kHz • Other models 9 kHz step: FM: 87.5 - 108 MHz AM: 531 - 1 602 kHz 10 kHz step: FM: 87.5 - 108 MHz AM: 530 - 1 710 kHz Antennas FM: Headphones cord antenna AM: Built-in ferrite bar antenna General Power requirements: • Two LR6 (size AA) batteries: 1.5 V DC × 2 • AC power adaptor (DC IN 4.5 V jack): 220 V, 50 Hz (Model for China) 120 V, 60 Hz (Model for Mexico) Photo : D-NF007 Dimensions (w/h/d) (without projecting parts and controls): Approx. 139.8 × 28.8 × 139.8 mm (5 5⁄8 × 1 3⁄16 × 5 5⁄8 in.) Mass (excluding accessories): Approx. 219 g (7.8 oz.) Operating temperature: 5°C - 35°C (41°F - 95°F) MPEG Layer-3 audio coding technology and patents licensed from Fraunhofer IIS and Thomson. Design and specifications are subject to change without notice. Supplied accessories AC power adaptor (1) (not supplied with the USA model) Headphones (1) Battery life* (approx. hours) (When the CD player is used on a flat and stable place.) Playing time varies depending on how the CD player is used. When using two Sony alkaline batteries LR6 (SG) (produced in Japan) G-PROTECTION G-on G-off Audio CD 16 11 MP3 CD (Recorded at 128 kbps) 23 23 RADIO ON 35 * Measured value by the standard of JEITA (Japan Electronics and Information Technology Industries Association). Design and specifications are subject to change without notice. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 2 D-NF007/NF0070 Notes on chip component replacement • Never reuse a disconnected chip component. • Notice that the minus side of a tantalum capacitor may be damaged by heat. Flexible Circuit Board Repairing • Keep the temperature of the soldering iron around 270 ˚C during repairing. • Do not touch the soldering iron on the same conductor of the circuit board (within 3 times). • Be careful not to apply force on the conductor when soldering or unsoldering. CAUTION Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure. TABLE OF CONTENTS 1. SERVICING NOTES ................................................ 3 2. GENERAL ................................................................... 3 3. DISASSEMBLY 3-1. Disassembly Flow ........................................................... 4 3-2. Upper Lid Assy, Cabinet (Middle) Assy, Cabinet (Lower) Assy ...................................................... 4 3-3. Optical Pick-Up (CDM-3525A), Main Board................. 5 4. ELECTRICAL ADJUSTMENT ............................. 6 5. DIAGRAMS 5-1. Block Diagram – CD/Power Section –........................... 10 5-2. Block Diagram – Tuner Section – .................................. 11 5-3. Printed Wiring Board – Main Board (Side A) – ............. 12 5-4. Printed Wiring Board – Main Board (Side B) – ............. 13 5-5. Schematic Diagram – Main Board (1/3) – ..................... 14 5-6. Schematic Diagram – Main Board (2/3) – ..................... 15 5-7. Schematic Diagram – Main Board (3/3) – ..................... 16 5-8. IC Pin Function Description ............................................ 20 6. EXPLODED VIEWS ................................................. 23 7. ELECTRICAL PARTS LIST .................................. 24 UNLEADED SOLDER Boards requiring use of unleaded solder are printed with the lead- free mark (LF) indicating the solder contains no lead. (Caution: Some printed circuit boards may not come printed with the lead free mark due to their particular size.) : LEAD FREE MARK Unleaded solder has the following characteristics. • Unleaded solder melts at a temperature about 40°C higher than ordinary solder. Ordinary soldering irons can be used but the iron tip has to be applied to the solder joint for a slightly longer time. Soldering irons using a temperature regulator should be set to about 350°C. Caution: The printed pattern (copper foil) may peel away if the heated tip is applied for too long, so be careful! • Strong viscosity Unleaded solder is more viscous (sticky, less prone to flow) than ordinary solder so use caution not to let solder bridges occur such as on IC pins, etc. • Usable with ordinary solder It is best to use only unleaded solder but unleaded solder may also be added to ordinary solder. SAFETY-RELATED COMPONENT WARNING!! COMPONENTS IDENTIFIED BY MARK 0 OR DOTTED LINE WITH MARK 0 ON THE SCHEMATIC DIAGRAMS AND IN THE PARTS LIST ARE CRITICAL TO SAFE OPERATION. REPLACE THESE COMPONENTS WITH SONY PARTS WHOSE PART NUMBERS APPEAR AS SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUBLISHED BY SONY. ATTENTION AU COMPOSANT AYANT RAPPORT À LA SÉCURITÉ! LES COMPOSANTS IDENTIFIÉS PAR UNE MARQUE 0 SUR LES DIAGRAMMES SCHÉMATIQUES ET LA LISTE DES PIÈCES SONT CRITIQUES POUR LA SÉCURITÉ DE FONCTIONNEMENT. NE REMPLACER CES COMPOSANTS QUE PAR DES PIÈCES SONY DONT LES NUMÉROS SONT DONNÉS DANS CE MANUEL OU DANS LES SUPPLÉMENTS PUBLIÉS PAR SONY. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 3 D-NF007/NF0070 SECTION 1 SERVICING NOTES NOTES ON HANDLING THE OPTICAL PICK-UP BLOCK OR BASE UNIT The laser diode in the optical pick-up block may suffer electrostatic break-down because of the potential difference generated by the charged electrostatic load, etc. on clothing and the human body. During repair, pay attention to electrostatic break-down and also use the procedure in the printed matter which is included in the repair parts. The flexible board is easily damaged and should be handled with care. NOTES ON LASER DIODE EMISSION CHECK The laser beam on this model is concentrated so as to be focused on the disc reflective surface by the objective lens in the optical pick- up block. Therefore, when checking the laser diode emission, observe from more than 30 cm away from the objective lens. LASER DIODE AND FOCUS SEARCH OPERATION CHECK During normal operation of the equipment, emission of the laser diode is prohibited unless the upper lid is closed while turning ON the S811. (push switch type) The following checking method for the laser diode is operable. • Method: Emission of the laser diode is visually checked. 1. Open the upper lid. 2. With a disc not set, turn on the S811 with a screwdriver having a thin tip as shown in Fig.1. 3. Press the u button. 4. Observing the objective lens, check that the laser diode emits light. When the laser diode does not emit light, automatic power control circuit or optical pick-up is faulty. In this operation, the objective lens will move up and down 2 times along with inward motion for the focus search. Fig. 1 Method to push the S811 S811 SECTION 2 GENERAL This section is extracted from instruction manual. LOCATING THE CONTROLS PRESET LOCAL MONO MP3 indicator Remaining battery power Track number/Preset number Playing time/Frequency MONO Group indicator * The button has a tactile dot. Display u*(play/pause)/ENTER (group) –/+ • DC IN 4.5 V i (headphones) jack x (stop)•RADIO OFF HOLD (rear) VOL +*/– to an AC outlet AC power adaptor Headphones SOUND/AVLS ./>• TUNE –/+ P MODE/ OPEN Play mode LOCAL RADIO ON/BAND GROUP Sound mode PRESET Band www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 4 D-NF007/NF0070 SECTION 3 DISASSEMBLY • This set can be disassembled in the order shown below. 3-1. DISASSEMBLY FLOW 3-2. UPPER LID ASSY, CABINET (MIDDLE) ASSY, CABINET (LOWER) ASSY Note: Follow the disassembly procedure in the numerical order given. 3-2. UPPER LID ASSY, CABINET (MIDDLE) ASSY, CABINET (LOWER) ASSY (Page 4) 3-3. OPTICAL PICK-UP (CDM-3525A), MAIN BOARD (Page 5) SET 4 screw upper lid assy cabinet (middle) assy cabinet (lower) assy 3 five screws 2 5 two claws 6 three claws 1 open www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 5 D-NF007/NF0070 3-3. OPTICAL PICK-UP (CDM-3525A), MAIN BOARD MAIN board (side A) to optical pick-up BLK ORG RED GRY 5 MAIN board cabinet (lower) assy 4 optical pick-up CDM-3525A 1 CN501 2 3 Unsolder four lead wires www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 6 D-NF007/NF0070 SECTION 4 ELECTRICAL ADJUSTMENTS [TUNER SECTION] CLOCK SHIFT ADJUSTMENT Connection: Adjusting Procedure: 1. Connect the frequency counter to TP471 (SIFT) and TP005 (RFGND (A)) or TP003 (RFGND (B)) on the MAIN board. 2. Set the AM 621 kHz (9kHz step model) or AM 620 kHz (10kHz step model) 3. Adjust the RV471 so that the reading of frequency counter is 180 ± 1 kHz. 0 dB=1 µV [AM] Setting: Function: RADIO Band: AM AVLS: OFF [FM] Setting: Function: RADIO Band: FM AVLS: OFF • Repeat the procedures in each adjustment several times, and the tracking adjustments should be finally done by the trimmer capacitors. + – frequency counter TP471 (SIFT) TP005 (RFGND (A)) or TP003 (RFGND (B)) MAIN board AM RF signal generator 30% amplitude modulation by 400 Hz signal Output level: as low as possible Put the lead-wire antenna close to the set. + – level meter set 32 Ω MAIN board TP005 (RFGND (A)) or TP003 (RFGND (B)) MAIN board TP012 (TU_L) or TP014 (TU_R) FM RF signal generator 33.75 kHz frequency deviation by 1 kHz signal Output level: as low as possible + – level meter set 32 Ω 0.01 µF MAIN board TP002 (RF (A)) or TP001 (RF (B)) MAIN board TP005 (RFGND (A)) or TP003 (RFGND (B)) MAIN board TP005 (RFGND (A)) or TP003 (RFGND (B)) MAIN board TP012 (TU_L) or TP014 (TU_R) digital voltmeter TP006 (VT) TP005 (RFGND (A)) or TP003 (RFGND (B)) 100 kΩ MAIN board ( ): 9kHz step model AM IF ADJUSTMENT Adjust for a maximum reading on level meter T002 620 (621) kHz ( ): 9kHz step model AM FREQUENCY COVERAGE CONFIRMATION Adjustment Part Frequency Display Reading in Digital Voltmeter Confirmation 530 (531) kHz 0.8 ± 0.5 V Confirmation 1,710 (1,602) kHz 7.2 (6.8) ± 1.0 V ( ): 9kHz step model AM TRACKING ADJUSTMENT Adjust for a maximum reading on level meter T001 620 (621) kHz CT001 1,400 (1,404) kHz FM FREQUENCY COVERAGE ADJUSTMENT Adjustment Part Frequency Display Reading in Digital Voltmeter Confirmation 87.5 MHz 2.8 ± 1.0 V L004 108 MHz 8.0 ± 1.0 V FM TRACKING ADJUSTMENT Adjust for a maximum reading on level meter L003 98 MHz Adjustment and Connecting Location: MAIN board (See page 7) Ver. 1.1 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 7 D-NF007/NF0070 Adjustment and Connecting Location: (SIDE A) MAIN BOARD TP001 (RF(B)) TP005 (RFGND(A)) CT001: L003: FM Tracking Adjustment RV471: Clock Shift Adjustment AM Tracking Adjustment IC601 1 20 21 40 41 60 61 80 TP006 (VT) TP003 (RFGND(B)) TP002 (RF(A)) TP014 (TUR) TP012 (TUL) TP471 (SIFT) (SIDE B) MAIN BOARD T001: T002: AM IF Adjustment L004: FM Frequency Coverage Adjustment AM Tracking Adjustment IC602 1 50 25 26 IC001 1 30 15 16 T001 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 8 D-NF007/NF0070 [CD SECTION] The CD section adjustments are done automatically in this set. Adjusting Procedure: 1. Perform check in the order given. 2. Use YEDS-18 disc (Part No: 3-702-101-01) unless otherwise indicated. 3. Power supply voltage requirement :DC4.5 V in DC IN jack. (J401) VOLUME button : Minimum HOLD switch :OFF Focus bias Check Condition: • Hold the set in horizontal state. Connection: C805 48 C472 C473 C474 C812 C806 C877 C001 2 C814 R411 R020 R472 R476 R473 R873 R826 R828 R812 R808 R876 R821 R872 R844 R804 R843 R824 R871 R874 3 R021 R474 R475 R477 C040 C049 C478 C471 C874 C880 R1019 R1016 R1017 R1011 R1012 R1003 R1018 R1015 R1010 R1014 IC1001 1 15 16 30 SL871 Q804 ECB Q475 ECB D871 RV471 (AEP) (EXCEPT AEP) IC802 IC471 1 1 8 8 4 4 5 5 D004 SL801 OPEN SL801(OPEN) (SIDE A) MAIN BOARD C627 C046 C035 C011 C020 C018 C102 C037 C635 C620 C633 C632 C634 C606 C612 C626 C605 C109 C209 C301 C624 C638 C910 C022 C024 C006 R605 R604 R603 R016 R630 R621 R626 R606 R615 R613 R632 R303 R906 R618 R622 R902 R901 R902 RB901 R004 R001 R002 R627 R013 R018 R220 R024 R012 R011 R109 R007 R014 R617 R601 R620 R204 R203 R103 R905 R904 C043 C045 C021 C023 C109 C031 C032 C631 C615 C609 C905 C906 C907 C005 C002 C003 C014 FB604 FB605 FB901 FB606 FB601 FB201 D002 D003 L005 R1004 TAP001 TAP003 RF GND(B) D001 1 16 8 IC901 9 Q102 Q101 IC603 IC602 1 50 25 26 IC001 30 5 16 S D G X001 1 3 4 5 IC1 40 41 TP006 VT TP013 GND TP604 RF TP014 TUR TP002 RF(A) TP012 TUL TP406 M-GND R1008 R1009 01 FL001 X601 RED GREEN NATURAL oscilloscope (AC range) + – TP604(RF) TP406(M-GND) (SIDE B) MAIN BOARD Procedure: 1. Make a solder bridge to short SL801 (OPEN) on the MAIN board side A. 2. Connect the oscilloscope to the test point TP604 (RF) and TP406 (M-GND) on the MAIN board side B. 3. Set a disc. (YEDS-18) 4. Press the u button. 5. Check the oscilloscope waveform is as shown below. A good eye pattern means that the diamond shape ( ) in the center of the waveform can be clearly distinguished. RF Signal reference Waveform (Eye Pattern) To watch the eye pattern, set the oscilloscope to AC range and increase the vertical sensitivity of the oscilloscope for easy watch-ing. 6. Stop revolving of the disc motor by pressing the x button. 7. SL801 is opened by taking the solder bridge. RF level 1.2 ± 0.2 Vp-p VOLT/DIV : 500 mV (With the 10 : 1 probe in use) TIME/DIV : 500ns Ver. 1.1 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 9 9 D-NF007/NF0070 D-NF007/NF0070 SECTION 5 DIAGRAMS Note on Printed Wiring Boards. • X : parts extracted from the component side. • Y : parts extracted from the conductor side. • a : Through hole. • f : internal component • : Pattern from the side which enables seeing. (The other layers' patterns are not indicated.) • Note for Printed Wiring Boards and Schematic Diagrams Note on Schematic Diagrams. • All capacitors are in µF unless otherwise noted. (p: pF) 50 WV or less are not indicated except for electrolytics and tantalums. • All resistors are in Ω and 1/4 W or less unless otherwise specified. • f : internal tolerance. • C : panel designation. • A : B+ Line. • H : adjustment for repair. • Power voltage is dc 3 V and fed with regulated dc power supply from battery terminal. • Voltages and waveforms are dc with respect to ground under no-signal (detuned) conditions. no mark : CD PLAY ( ) : FM [ ] : AM • Voltages are taken with a VOM (Input impedance 10 MΩ). Voltage variations may be noted due to normal produc- tion tolerances. • Waveforms are taken with a oscilloscope. Voltage variations may be noted due to normal produc- tion tolerances. • Circled numbers refer to waveforms. • Signal path. J : CD PLAY F : FM f : AM • Abbreviation 3AEP : UK model 8E19 : Philippines model AUS : Australian model CND : Canadian model E19 : Singapore model EE : East European model Caution: Pattern face side: Parts on the pattern face side seen from (Side B) the pattern face are indicated. Parts face side: Parts on the parts face side seen from (Side A) the parts face are indicated. • Waverforms 3 IC001 qg X O (RADIO mode) 1 V/DIV, 5 µs/DIV 13.75 µs 1.6 Vp-p 1 IC601 ya XO (CD play mode) 0.5 V/DIV, 20 ns/DIV 2 IC801 yd XOUT4M (CD play mode) 1 V/DIV, 50 ns/DIV 59 ns 1.8 Vp-p 126 ns 3.5 Vp-p • Abbreviation 3AEP : UK model 8E19 : Philippines model AUS : Australian model CND : Canadian model E19 : Singapore model EE : East European model Note: The components identified by mark 0 or dotted line with mark 0 are critical for safety. Replace only with part number specified. Note: Les composants identifiés par une marque 0 sont critiques pour la sécurité. Ne les remplacer que par une piéce portant le numéro spécifié. w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 10 10 D-NF007/NF0070 D-NF007/NF0070 5-1. BLOCK DIAGRAM –CD/POWER SECTION– : CD PLAY : FM • Signal Path 6 5 22 24 55 23 50 53 49 47 48 39 3 57 6 9 18 DRIVER DRIVER DRIVER 17 19 20 23 22 11 OP IC TRK 31 21 32 SWITCHING Q404 SWITCHING Q473,474,480 SWITCHING Q403 17 16 15 19-24,27-32 2,3,5,6,8,9,11,12,39, 40,42,43,45,46,48,49 41 40 2 - 21 77 - 80 LCD801 LIQUID CRYSTAL DISPLAY KEY MATRIX SUBSYQ MCK DIN OUT RW EE_SCL 56 HP_MUTE EE_SDA/REM_SDA XXRESET BUSY 51 FIFO LINEOUT_MUTE MUTE2 RESETB SEG1 I SEG20 COM1 I COM4 OPEN/CLOSE HOLD 67 KEY1 63 XOUT8M 62 XIN8M 68 KEY2 REGB 65 DC IN TU_CTL 30 DCIN IC801(1/2) SYSTEM CONTROL D403 FB404 F402 F401 FB405 DDC REG0 PVCC +VBAT DDC Q471 TU-VCC L402 L403 TUNER:H 38 VSYS 37 SW OUT1 OUT2 IN1 IN2 SDA SCL 7 WP 8 VCC 2 MUTE IC301 HEADPHONE AMP IC802 EEPROM IC401 (2/2) DC/DC CONVERTER 5 VOUT VDD_CORE 1 VIN IC603 REG CD-VCC FO+ FO- TRK- TRK+ SLED+ SLED- AMP 10 FOCUS AMP 8 AMP 7 CLV RV471 CLOCK SHIFT SHIFT:L TRK FOCUS VREF SLED CLV CLK AMP RESET 74 2 P.OFF OFF 76 4 MUTE34 75 5 MUTE1 MUTE1 44 K_TUNER IC401 (1/2) FOCUS/TRACKING COIL DRIVE, SLED/SPINDLE MOTOR DRIVE IC602 SDRAM(16M) RAS CAS WE DQ0-15 A0-11 14 36 LDQM UDQM 35 34 CLK CKE J401 DC IN 4.5V ! DRY BATTERY SIZE "AA" (IEC DESIGNATION LR6) 2PCS. 3V REMOTE i (SLED) FOCUS COIL (SPINDLE) M TRACKING COIL F+ F- T+ T- SLED+ SLED- DRIVER 25 24 SPID+ SPIN- M SPINDLE+ SPINDLE- OPTICAL PICK-UP (CDM-3525A) VCC A B C E F LD LD-PD VC LD DRIVER Q601 CD-VCC S811 (OPEN) X801 75kHz S812 HOLD OFF ON REG Q603 D871 RADIO ON BAND S871 S802 - S809 Q472 VDD DSP Q479 CD-VCC C TUNER SECTION (Page 11) ANT A TUNER SECTION (Page 11) D TUNER SECTION (Page 11) TU R TU L B TUNER SECTION (Page 11) 43 1 29 K_PLAY WP D872 S801 ENTER 5 3 CLOCK SHIFT IC471 2 6 7 1 5 3 INVERTER IC1002 SWITCHING Q475 SWITCHING Q477 CD-VCC SWITCHING Q476 VDD DSP CT +B SWITCH Q401 DC IN DETECT Q402 3 80 79 67 2 10 4 6 7 13 14 15 16 75 63 60 61 53 57 50 51 52 54 DIGITAL SIGNAL PROCESSOR SERVO SIGNAL GEN. RF SIGNAL GEN. DIGITAL SERVO SIGNAL PROCESSOR PD LD FDOUT TDOUT SDSOUT CLVOUT FOCUS 56 CLK88 CLK TRK SLED CLV XO XI SUBSYQ MCK DIN/DOUT R/W RESTB BUSY CLOCK OSC 1 BIT DAC LINE AMP 39,42-48 32-21 MP3 & ADPCM CORE 65 X601 16.9344MHz RDACO LDACO Q602 BD AC E F ASY VBIAS RASX A00-A11 DQ00-07 RFI EQO CASX WEX LDQM UDQM 34 35 36 37 38 RCLK FLAG0 AD_MONI0 RCKE A13 17 18 19 IC601 RF AMP, SERVO, DIGITAL SIGNAL PROCESSOR, SDRAM CONTROLLER, D/A CONVERTER APC 9 8 X8 OVER SAMPLING DIGITAL FILTER 16K SRAM 45 54 28 32 26 27 25 30 31 66 60 CHG_CLK IFMUTE IFBUSY IFRDY SYSBUSY IFACK 59 XIN75 SYSREQ SYSSEL IFRST CHG_CLK IFMUTE IFBUSY IFRDY SDA SCL SYSBUSY IFACK SYSREQ SYSSEL IFRST BATT+ XOUT75 INVERTER Q475 MUTE Q101,201 INVERTER Q475 X802 8MHz 30 28 27 25 24 CHG_CLK IFMUTE IFBUSY SCL 6 CK_CTL2 XTIN 2 XIN 3 XOUT CK_CTL 11 IC1001(2/2) TUNER CONTROLLER 23 22 21 18 SDA IFRDY SYSBUSY IFACK 17 16 9 SYSREQ SYSSEL CHG_CLK IFMUTE IFBUSY SCL SDA IFRDY 8 RESET RESET SYSBUSY IFACK SYSREQ SYSSEL WSYSREQ 3 5 1 7 + + J301 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 11 11 D-NF007/NF0070 D-NF007/NF0070 5-2. BLOCK DIAGRAM –TUNER SECTION– B C D CD/POWER SECTION (Page 10) CD/POWER SECTION (Page 10) CD/POWER SECTION (Page 10) FM TRACKING FM FREQUENCY COVERAGE L003 AM IF T002 AM TRACKING CT001, T001 L004 1 FM/TV MIX FM/TV RF IN FM TV MIX OUT FM IF IN AM IF IN XI XO INV TUNER:H SHIFT:L TUNER:H SHIFT:L DO TU-CE CLK D-I/O PLL VCC PLL GND X001 LPF2 PLL LPF1 R OUT L OUT TU L TU R FM IF IF BUFFER AF DET OUT MPX IN TU-VCC CF002 CF001 T002 (AM IFT) FM RF OUT L003 (FM RF) L004 (FM OSC) L001 AM FERRITE-BAR ANTENNA T001 (AM OSC) D002 CT001 D001 TU-VCC (VT) D004 T003 TU-VCC ANT FL001 TV RF OUT RF VCC FM/TV OSC AM RF IN AM OSC VOL_EN TCK TDO TDI IC001 FM RF AMP, FM/AM OSC, FM/AM IF AMP, FM/AM DET, FM MPX, PLL IC901 TU VOLUME IC801(2/2) SYSTEM CONTROL 30 29 28 26 AM MIX AGC PC 1/8 FM OSC IN IF IN FM AM AM OSC IN AGC 1/2 27 4 LPF Q002 INVERTER Q001 DC-DC CONVERTOR Q003 25 AM OSC 5 9 TU-VCC TU-VCC DDC TU-VCC TU-VCC CF003 QUAD 8 AM IF FM DET AM DET FM MPX MUTE FM/AM/TV SWITCH REFERENCE DIVIDER PROGRAM COUNTER 3 13 14 11 12 16 15 19 20 17 21 22 23 24 18 CD/POWER SECTION (Page 10) A 37 36 35 34 D003 BPF 7 R OUT DVDD MLEN MCK MDT AVDD L OUT 5 12 7 4 15 16 14 R IN L IN 6 11 FM_H PLL_CE TCK TDO TDI IC1001(1/2) TUNER CONTROLLER 10 12 13 36 35 1/16 1/4 BUFFER FM/TV1/2 FM1/32 TV1/8 AM 10 : AM : FM • Signal Path w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 12 12 D-NF007/NF0070 D-NF007/NF0070 5-3. PRINTED WIRING BOARD – MAIN BOARD (SIDE A) – :Uses unleaded solder. 2 3 4 5 6 7 8 9 A 1 B C D E F G H 12 (12) 1-868-220- C407 C450 C807 C805 C048 C047 C472 C473 C474 C815 C875 C402 C808 C811 C812 C806 C877 VDR802 C882 C802 C814 C470 C619 C625 C618 C101 C201 C205 C105 R847 R484 R849 R404 R810 R026 R411 R022 R020 R472 R476 R473 R873 R826 R828 R812 R808 R823 R876 R821 R872 R850 R614 R036 R402 L008 R006 R009 R104 R305 R877 R844 R804 R843 R824 R871 R408 R835 R483 R829 R874 R848 R846 R845 R817 R403 R419 R418 R417 R416 R480 R481 R023 R021 R474 R475 R477 R629 R301 R401 F402 R005 R307 R308 R619 R624 R811 C008 C403 C405 C475 C480 C040 C049 C478 C471 C809 C874 C880 C876 C611 C604 C637 C044 C042 C041 C401 C027 C010 C908 C901 C902 C903 C909 C202 C102 C303 C108 C208 FB301 IC301 1 4 8 5 RB305 RB302 RB304 RB303 RB620 CT001 L003 CF001 CF002 FB404 FB403 D420 D404 L407 L406 R1019 R1013 R1016 R1017 R1011 R1012 R1003 R1018 R1015 R1010 R1014 IC1001 1 15 16 30 SL871 Q804 ECB Q803 BCE Q477 BCE Q475 ECB D871 RV471 (AEP) (EXCEPT AEP) IC802 IC471 1 1 8 8 4 4 5 5 L006 D004 Q003 BCE SL803 SL801 OPEN RB806 Q476 ECB D403 D401 Q401 Q402 ORG GRY BLK RED L450 R412 R482 R851 R410 Q479 ECB FB603 IC601 1 20 21 40 41 60 61 80 VDR418 Q602 ECB MAIN BOARD (SIDE A) + – + – (SLED) M (SPINDLE) M OPTICAL PICK-UP (CDM-3525A) (1/2) TAP005 RF GND(A) TAP001 RF(B) • Semiconductor Location Ref. No. Location D004 F-2 D401 G-4 D403 G-4 D404 E-8 D420 E-8 D871 E-1 IC301 B-4 IC471 F-2 IC601 D-4 IC802 F-2 IC1001 E-3 Q003 F-2 Q401 G-4 Q402 G-4 Q475 E-2 Q476 G-4 Q477 E-3 Q479 D-2 Q602 C-5 Q803 F-4 Q804 F-4 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 13 13 D-NF007/NF0070 D-NF007/NF0070 5-4. PRINTED WIRING BOARD – MAIN BOARD (SIDE B) – :Uses unleaded solder. 2 3 4 5 6 7 8 9 A 1 B C D E F G H C481 C406 C453 C452 C413 C881 C810 C827 C627 C046 C025 C026 C030 C038 C039 C028 C050 C029 C034 C017 C016 C035 C011 C020 C018 C012 C037 C629 C620 C633 C632 C634 C606 C612 C626 C605 C109 C209 C301 C624 C638 C910 C022 C024 C006 R485 R414 R407 CB414 R879 R875 R882 R605 R604 R603 R880 R030 R016 R675 R852 R853 R630 R621 R626 R606 R608 R615 R613 R632 R101 R201 R111 R303 R906 R618 R622 R902 R901 R902 RB901 RB301 R004 R001 R002 R471 R478 R415 R856 R881 R406 R405 R409 R820 R672 R013 R018 R015 R024 R012 R011 R017 R027 R008 R109 R007 R014 R617 R673 R602 R854 R674 R607 R601 R620 R211 R304 R202 C206 R102 C106 R204 R203 R103 R905 R904 C476 C477 C421 C417 C412 C410 C411 C813 C603 C454 C033 C036 C009 C043 C045 C021 C023 C019 C031 C032 C640 C631 C615 C609 C110 C210 C004 C905 C906 C907 C005 C002 C003 C014 FB604 FB605 F401 FB901 FB606 FB101 FB402 FB401 FB601 FB305 FB201 D201 (AEP,3AEP,EE) D101 D002 D003 L005 L002 C416 C1001 R1005 R1001 R1004 L403 L007 TAP001 TAP003 RF GND(B) D001 1 16 8 IC901 9 Q102 Q101 Q603 BCE IC603 IC602 1 50 25 26 IC001 1 30 15 16 S D G X001 Q002 L004 Q001 ECB D402 Q601 1 3 4 5 1 3 4 5 ECB IC1002 CN801 IC801 1 20 21 40 41 60 61 80 IC401 1 20 21 40 X802 D872 Q404 BCE Q471 BCE Q474 ECB Q473 ECB Q480 ECB Q472 ECB Q403 ECB TP006 VT TP013 GND TP802 OPEN TP604 RF TP014 TUR TP002 RF(A) TP012 TUL TP471 SIFT TP406 M-GND R1008 R1009 TP416 SLED+ TP416 SLED- TP416 SPINDLE- TP416 SPINDLE+ MAIN BOARD (SIDE B) 12 (12) 1-868-220- T001 FL001 C104 C607 C602 C610 C601 C623 OFF ON C628 C204 C305 C304 S871 T003 RADIO OFF ENTER TUNE TUNE C409 C404 C408 C419 C420 L402 C013 T002 CF003 DC IN 4.5V J401 CN501 X801 i J301 REMOTE S811 (OPEN) S804 VOL+ S808 SOUND/AVLS S805 VOL– S809 P MODE/ S806 RADIO ON BAND GROUP 24 1 LCD801 LIQUID CRYSTAL DISPLAY S803 . S802 > S807 x S801 u DRY BATTERY SIZE "AA" (IEC DESIGNATION LR6) 2PCS. 3V 1 2 15 16 OPTICAL PICK-UP (CDM-3525A) (2/2) X601 RED GREEN NATURAL L001 AM FERRITE-BAR ANTENNA S812 HOLD. T • Semiconductor Location Ref. No. Location D001 C-4 D002 C-4 D003 D-4 D101 B-7 D201 B-7 D402 E-3 D872 H-6 IC001 C-3 IC401 G-6 IC602 D-5 IC603 D-6 IC801 F-7 IC901 C-5 IC1002 E-7 Q001 D-3 Q002 D-4 Q101 B-6 Q102 B-6 Q403 F-5 Q404 G-5 Q471 F-5 Q472 F-5 Q473 F-5 Q474 F-5 Q480 F-5 Q601 D-7 Q603 D-7 Ver. 1.1 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 14 14 D-NF007/NF0070 D-NF007/NF0070 5-5. SCHEMATIC DIAGRAM – MAIN BOARD (1/3) – • See page 9 for Waveforms. • See page 9 for IC Block Diagrams. D002 D003 D004 C002 C003 C005 C008 C010 C014 C024 C006 C020 C012 C023 C011 C018 C021 C027 C044 C031 C032 C035 C040 C037 C046 C043 C045 C026 C028 C029 C030 C034 C036 C041 C042 Z002 C013 C017 C910 R904 R905 R906 C905 C902 C903 R901 R902 C048 TAP001 FL001 R006 R004 R001 R005 R009 R014 R016 R020 R023 R022 R021 R011 R012 R019 R013 R018 R036 R008 R027 R017 C016 R002 L003 L004 C019 Q002 TP001 TP002 TP003 TP006 T001 CT001 IC001 CF001 T002 CF002 CF003 C907 T003 Q003 C047 C049 C906 D001 R031 C022 TP005 L002 C050 C038 C039 TP012 TP014 RB901 C909 L007 RB902 R1008 R1009 IC901 FB901 R007 C009 C033 R030 X001 C901 R026 R024 R015 C025 Q001 C908 L005 L006 L008 HVC202B TRU HVC202B TRU 1SS355TE-17 2200p 0.022 0.1 220p 150p 0.022 220p 5p 0.01 0.01 4.7 0.01 5p 150p 1000p 1000p 0.01 0.22 2.2 0.01 1 4.7 15p 22p 0.1 0.1 470p 0.1 1 0.1 0.1 0.1 47 6.3V 0.1 1000p 220 220 220 1 4.7 4.7 10 10 4.7 22 470k 470k 470k 10k 15k 47k 10k 220 100k 1k 220 220 10k 0 0 0 470 22 3.3k 1000p 1k 0.01 2SK3019TL LPF RF(B) RF(A) RF GND(B) VT AM OSC 10p TB2132FNG 10.7MHz AM IFT 450KHz 10.7MHz 1 DC-DC CON 2SC4154-F DC/DC CONVERTER 5p 0.01 1 0 5p RF GND(A) 0H 0.01 TUL TUR 0 2200p 0 4.7k 1k 1k SM6451BV-E2 0 0.01 0.1 0 75kHz 4.7 220 47k 220 4.7 RT1P140M-TP-1 INVERTER 0 0H 0H 0H TU L TU R GND BUS 2 ANT SIFT:L DDC TUNER:H FM/AM TU GND TU VCC TCK TU CE TCK VOL EN TDO TDI 0.01 0.01 1 FM/TV I GND MIX O AGC FM-IF I AM-IF I VCC QUAD DET-O MPX IN LPF1 LPF2 L O R O X O X I D-GND SIFT:L TUNER:H DO VDD D I/O CLK TU-CE AM-OSC FM/TV-OSC AM-RF RF-VCC TV-RF O FM-RF O VRL AVDD LIN LOUT DVDD ADRS2 ADRS1 RSTN VRR AVSS RIN DVSS MLEN MCK MDT ROUT AM FERRITE-BAR ANTENNA L001 S BOARD MAIN BOARD MAIN (2/3) (Page 15) (3/3) (Page 16) FM TRACKING FREQUENCY COVERAGE FM TRACKING AM L003 FM RF L004 FM OSC FM/TV/AM IF AMP,FM/AM DET, FM MPX,PLL FM/TV RF AMP,FM/TV/AM OSC, AM IF T002 TU VOLUME CT001,T001 1 R007 NF007: EXCEPT CND 1k 2.2k NF007: CND/NF0070 * * w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 15 15 D-NF007/NF0070 D-NF007/NF0070 5-6. SCHEMATIC DIAGRAM – MAIN BOARD (2/3) – • See page 9 for Waveforms. • See page 18, 19 for IC Block Diagrams. D401 D403 L406 47uH 47uH L407 C410 C412 C403 CB414 R417 R418 R419 R623 C615 C609 C606 R606 R613 R614 C610 C611 C618 C620 C625 R619 R618 RB620 C406 R102 R202 R111 R211 C104 RB301 R101 R201 C110 C210 C301 C204 R406 C413 C626 R305 C603 CN407 CN408 IC401 R403 R405 C305 C624 C206 C106 C108 C208 R407 C303 CN501 IC601 IC602 C629 R811 R629 C105 C205 C102 C202 C101 C201 RB303 RB304 R307 R308 FB601 Q402 R605 R603 R604 C601 C602 R615 DQ01 DQ02 DQ03 DQ04 DQ05 DQ06 A00 A01 A02 A03 A04 A05 A06 A07 A08 A09 A10 A11 A12 A13 R630 FB301 R622 C631 R626 C407 R409 DQ00 C637 C633 C627 IC301 X601 R601 R620 R608 R607 R416 C612 C619 R624 FB606 IC603 C634 C632 FB603 R672 R621 R480 R481 C109 C209 R103 R203 R204 R104 C471 C472 C473 C474 C478 R482 R411 R472 R473 R474 R475 RV471 R476 R477 Q475 Q477 Q476 IC1001 IC1002 R1014 R850 R1001 R1010 R1011 R1012 R1013 R1015 R1016 R1018 C1001 R1005 R1017 R1019 SL1001 FB604 FB605 R1003 CN403 CN404 FB401 Q601 R602 R673 R674 R675 C640 C454 C475 C450 C452 Q401 R617 C408 C409 L450 1000uH C453 TP604 C628 C638 Q602 RB302 C004 R303 FB101 FB201 AEP,3AEP,EE AEP,3AEP,EE D101 D201 R304 FB305 C304 RB305 C411 C604 Q101 Q102 Q603 C605 C607 IC471 C404 FB402 J301 UDZSTE-176.2B RB160M-30TR 0.1 1 0.1 0.022 100k 47k 22k 0 2200p 2200p 0.1 220k 68k 470 4.7 50V 0.22 470p 0.1 2.2 100k 1M 10k 0.1 2.2 2.2 10 10 220 6.3V 1k 10 10 1000p 1000p 0.1 220 6.3V 10k 0.022 0.01 220k 0.01 BH6575FV-E2 1k 12k 47 6.3V 0.1 0.22 0.22 470p 470p 27k 1 16P BU9541AKV M12L16161A-7T(G) 2.2 100k 0 2.2 2.2 1000p 1000p 2200p 2200p 470 470 0 0 0 UMH8N-TR DC IN DETECT 0 4.7 100k 47 6.3V 47 6.3V 68k 0 0H 220 0.1 220 10 0 0.1 0.1 4.7 BH3544F-FE2 16.9344MHz 10k 10k 10k 10k 22k 0.1 0.1 100k 0H BH15FB1WG 1 0.1 0 0 0 100k 100k 0.068 0.068 220 220 1M 1M 0.1 100p 10p 8p 470p 2.2k 470k 4.7k 10k 0 100k 10k 15k 470k RT1N140M-TP-1 SWITCHING RT1P140M-TP-1 SWITCHING RTN144MM-TP-1 SWITCHING TMP86C808DMG -6F65 BU4S584G2 0 0 0H 0 0 0 0 0 0 1M 10 22k 22k 0 0H 0H 0 0 2SA1602TP-1EF LD DRIVER 220 100k 4.7k 2.2 4.7 10 220p 1 1 2SB1132-T100-Q +B SWITCH 100 100 6.3V 10 16V 470p RF 10 16V 1 RT1N140M-TP-1 BUFFER 4.7k 220p 1M 0H 0H RSB6.8STE61 RSB6.8STE61 0 0H 100 6.3V 220k 220p 0.1 UMH8N MUTE UMD2N-TR MUTE SWITCH 2SA2018TL REG 0.1 47 6.3V TC7WH240FK 10 16V 0H GND BUS B+ D GND BUS 2 BUS 2 SIFT:L TU L TU R ANT FM/AM DDC VDD DSP CD VCC +VBAT A01 A02 A03 A10 A11 A00 DQ00 DQ01 DQ02 DQ03 DQ04 DQ05 DQ06 DQ07 WE CAS RAS CKE CLK 9 11 13 14 15 16 19 20 A04 A05 A06 A07 A08 A09 2 4 5 6 7 8 DQ07 WE CAS RAS A00 A01 A02 A03 A04 A05 A06 A07 A08 A09 A10 A11 CLK CKE 3 DQ00 DQ01 DQ02 DQ03 DQ04 DQ05 DQ06 UDQM DQ00 DQ01 DQ02 DQ03 DQ04 DQ05 DQ06 DQ07 UDQM LDQM LDQM 22 23 24 25 26 27 28 29 30 31 32 33 34 35 TCK TDO TU CE TDI PVCC SLED- SLED+ SPIND- SPIND+ DPG2 SPRT SOFT CT DCIN REGB REGO PRGND PGND LG VG SW VSYS EI EO TRK+ TRK- FO+ FO- FIL4 FIL3 FIL2 FIL1 VREF FOCUS TRK SLED CLV RESET MUTE1 MUTE34 CLK OFF WP VSS DQ15 DQ14 VSSQ DQ13 DQ12 VCCQ DQ11 DQ10 VSSQ DQ9 DQ8 VCCQ NC UDQM CLK CKE NC A9 A8 A7 A6 A5 A4 VSS VCC DQ1 VSSQ DQ2 DQ3 VCCQ DQ4 DQ5 VSSQ DQ6 DQ7 VCCQ LDQM WE CAS RAS CS A11 A10 A0 A1 A2 A3 VCC OUT1 IN1 GND IN2 BIAS OUT2 VCC RCLK RCKE WEX CASX RASX CLVOUT SDOUT TDOUT FDOUT FCO PCO ASY LD PD F E VBIAS BD AC AVDD1 EQO ANA MONI1 ANA MONI0 TEST AD MONI1 AD MONI0 AGND2 RDACO VCDAC LDACO AVDD2 XO XI 16M SDRAM C E A B F VCC VC GND GND LD NC F+ T+ T- F- FOCUS/TRACKING COIL DRIVE, SLED/SPINDLE MOTOR DRIVE, DC/DC CONVERTER DPG1 RFI AGND1 PROCESSOR, SD RAM CONTROLLER ,D/A CONVERTER RF AMP,SERVO,DIGITAL SIGNAL HEADPHONE AMP DQ0 BOARD MAIN HPRDAC0 VDD RD VSS RD VSS LD HPLDACO VDD LD FLAG0 DVDD2 DGND2 CLK88 CLK SUBSYQ BUSY MCK R/W DVDD1 VDD CORE1 LDQM UDQM DQ07 REG VIN VSS CE VOUT NC RESETB DIN/DOUT DGND1 TUNER CLOCK SHIFT G1 A1 Y2 GND VCC G2 Y1 A2 TDI TDO TCK PLL CE CK CTL1 FM H WSYSREQ RESET XTOUT XTIN VCPU TEST XOUT XIN GND SYSSEL SYSREQ IFACK NC NC SYSBUSY IFRDY SDA SCL IFBUSY NC IFMUTE AM SEL CK CTL2 (CHG CLK) Y VDD NC A VSS LD-PD MUTE (3/3) (Page 16) VDD CORE2 CONTROLLER CLOCK SHIFT INVERTER REMOTE BOARD MAIN (1/3) (Page 14) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 16 16 D-NF007/NF0070 D-NF007/NF0070 5-7. SCHEMATIC DIAGRAM – MAIN BOARD (3/3) – • See page 9 for Waveforms. • See page 20 for IC Pin Function Description. SEG1 SEG2 SEG3 SEG4 SEG5 SEG6 SEG7 SEG8 SEG9 SEG10 SEG11 SEG12 SEG13 SEG14 SEG15 SEG16 SEG17 SEG0 COM1 COM2 COM3 COM4 D402 D404 L402 165uH C416 C417 R414 R415 C419 L403 10uH C405 R404 S801 S804 S805 S808 S809 S812 R829 R826 R812 C805 RB806 C802 R821 C811 C809 C807 Q403 Q404 CN401 CN402 R844 R843 C808 S811 R402 R401 C401 J401 IC802 R835 F401 S806 R845 R846 R849 R851 R852 R853 R854 R817 VDR802 SEG18 SEG19 SEG20 SL803 F402 C480 R484 S871 R880 R881 D871 D872 R810 R874 R871 R872 C882 SL802 C402 R408 R873 R824 SL871 C810 SL801 R828 C815 R804 R808 CN801 D420 VDR418 FB403 4.7uH 4.7uH FB404 R485 Q479 Q472 Q471 Q480 Q473 Q474 C470 R410 R471 R478 R412 R483 C623 C421 C477 C420 C476 S803 S802 R847 R848 R856 S807 C876 C877 C875 C874 R876 R877 X802 R879 C880 R875 R1004 C813 C872 X801 R882 R820 C881 R823 C481 IC801 C812 C814 C806 Q803 Q804 TP471 TP406 RB160M-30TR UDZS-TE17-12B 47p 0.1 10 1k 220 6.3V 1000p 100 100k 0 100k 0.1 47k 0.01 100k 0.1 0.1 1 2SD2652T106 SWITCHING 2SD2652T106 SWITCHING 10k 10k 1 (OPEN) 22k 100k 1 BR24L02F-WE2 0H 2A 32V 10k 10k 2.2k 22k 2.2k 4.7k 22k 10k TEST 1.4A 32V 0.022 47k 470 470 MC2838 MC2838 1M 100k 1000p ICE 1000p 0H 2.2k 2.2k TU TEST 10 OPEN 2.2k 0.1 0 100k 24P UDZS-TE17-12B 1 0 2SA2018TL +B SWITCH 2SA2018TL +B SWITCH RT1P140M-TP-1 +B SWITCH RT1N140M-TP-1 SWITCHING RT1N140M-TP-1 SWITCHING RT1N144M-TP-1 SWITCHING 2200p 0.22 100k 4.7k 4.7k 10 470 6.3V 1 1 220 6.3V 1 2.2k 2.2k 4.7k 22p 22p 1000p 0.01 47k 47k 8MHz 1M 470p 1k 0 10p 12p 75kHz 0 2.2M 1000p 1k 47p BU18704-S5 470p 470p 0.1 2SC4081T106 INVERTER 2SC4081T106 INVERTER SIFT M GND BUS B+ D GND GND DDC TUNER:H TU VCC TU GND DDC BUS 2 +VBAT CD VCC VDD DSP COM1 COM2 COM3 COM4 SEG01 SEG02 SEG03 SEG04 SEG05 SEG06 SEG07 SEG08 SEG09 SEG10 SEG11 SEG12 SEG13 SEG14 SEG15 SEG16 2 11 3 4 5 6 7 20 15 13 16 8 9 14 19 SEG19 SEG20 SEG17 SEG18 COM1 COM2 COM3 COM4 SEG01 SEG02 SEG11 SEG12 SEG13 SEG14 SEG15 SEG16 SEG17 SEG18 SEG19 SEG20 SEG03 SEG04 SEG05 SEG06 SEG07 SEG08 SEG09 SEG10 32 33 34 TCK TDO TDI VOL EN 23 24 25 26 27 28 29 35 22 30 31 *1 *2 DC IN 4.5V DRY BATTERY SIZE"AA" (IEC DESIGNATION R6) HOLD ON OFF SDA SCL WP VCC GND A2 A1 A0 XOUT75 XIN75 TEST0 TU CTL VDD BUSY RW MCK DIN OUT K TUNER K PLAY OPEN/CLOSE EE SCL EE SDA/REM SDA GND SUBSYQ HOLD TEST1 SEL OPTION WREM BATT+ DC IN VDD GND LIQUID CRYSTAL DISPLAY SYSTEM CONTROL EEPROM BOARD MAIN SEL CEX KEY1 KEY2 1 5 10 15 20 24 FIFO (2/3) (Page 15) EXCEPT AEP AEP MMUTE1 MMUTE2 P.OFF NC TEST XIN8M XOUT8M RESETB HP MUTE IFMUTE NC (CHG CLK) TU TEST VOL EN TCK(IFCON&VOL CLK) TDO(IFCON&VOL DATA) TDI(IFCON) IFRDY IFRST SYSSEL IFBUSY IFACK SYSBUSY SYSREQ LINEOUT MUTE NF007: EXCEPT CND NF007: CND/NF0070 *1 R871 AEP,3AEP,EE E19,8E19,AUS 100k 220k *2 R872 47k 220k 2PCS.3V BOARD MAIN (1/3) (Page 14) RESET LINE DET w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 17 D-NF007/NF0070 • IC Block Diagrams IC001 TB2132FNG IC901 SM6451BT-G-E2 FM/TV RF IN 1 MIX OUT 3 GND 2 AGC 4 FM IFIN 5 FM RF TV RF FM/TV MIX AM MIX 27 AM RFIN 17 PLL GND 21 PLL VCC 18 OUT1 (ST) 26 FM/TV OSC 28 RF VCC 29 TV RFOUT 30 FM RFOUT FM IF AM IFIN 7 VCC 6 DET OUT 9 QUAD 8 MPX IN 10 LPF1 11 LPF2 12 AM IF AM DET FM DET L-CH 13 R-CH 14 XO 15 IF BUFFER AF FM MPX MUTE OSC 25 AM OSC 16 XI AM OSC 1/2 1/4 1/16 AM TV 1/8 FM 1/32 FM/TV 1/2 BUFFER AM OSCIN FM OSCIN PROGRAM COUNTER REFERENCE DIVIDER IFIN 1/8 AM FM FM/AM/TV SWITCH 22 DATA 19 OUT2 (DO2) 20 DO PHASE COMPARATOR 23 CK 24 CE PLL AGC 1 2 3 4 RSTN ADRS1 ADRS2 DVDD 5 6 7 8 16 15 14 13 12 11 10 9 LOUT LIN AVDD VRL 1/2VDD MDT MCK MLEN DVSS ROUT RIN AVSS VRR 1/2VDD ATTENUATION CONTROL REFERENCE VOLTAGE CIRCUITS ATTENUATION CONTROL ATTENUATION DECODER INTERFACE CONTROL CHIP ADDRESS DECODER www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 18 D-NF007/NF0070 IC401 BH6575FV-E2 IC471 TC7WH240FK EO SYSTEM ON OSC SYSTEM OFF CLK 30k 30k DC/DC CONVERTER – + – + – + VG CONV VSYS REG PRE-DR VSYS DETECT OFF 2 MUTE34 4 CLK 3 MUTE1 5 RESET 6 CLV 7 SLED TRK 9 VREF 11 FIL1 12 FIL2 13 FIL3 14 DPG1 16 TRK– TRK+ 19 20 FIL4 15 WP 1 40 SPIND– SLED+ SLED– PVCC 24 23 22 21 SPIND+ 25 SPRT 27 DPG2 26 SOFT 28 DCIN 30 CT 29 REGO 32 REGB 31 PRGND 33 PGND 34 VG 36 LG 35 VSYS 38 SW 37 EI 39 MUTE34 – – + RESET MUTE1 – + 8 30k – + – + – + – + 30k – + FOCUS 10 PRE-DR PRE-DR PRE-DR FO+ 18 FO– 17 1 2 3 4 G1 A1 Y2 GND 8 7 6 5 VCC G2 Y1 A2 IC301 BH3544F-FE2 + 6 7 5 8 + 2 1 3 4 OUT 1 XMUTE MUTE IN 1 GND VCC OUT 2 BIAS IN 2 BIAS TSD 24.7k 24.7k 16.9dB 16.9dB www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 19 D-NF007/NF0070 IC601 BU9541AKV MP3 & ADPCM CORE X8 OVER SAMPLING DIGITAL FILTER DIGITAL SIGNAL PROCESSOR DIGITAL SERVO SIGNAL PROCESSOR 16K SRAM SERVE SIGNAL GENERATOR RF SIGNAL GENERATOR APC D CLASS HP AMPLIFIER PLL LINE AMPLIFIER 1 BIT DAC AVDD1 AC BD VBIAS AGND1 E F PD LD ASY PCO FCO FDOUT TDOUT SDOUT CLVOUT RCLK RCKE A13 A12 A11 A10 A09 A08 A07 A06 A05 A04 A03 A02 A01 A00 VDD_CORE1 DGND RASX CASX WEX LDQM UDQM DQ07 SUBSYQ BUSY MCK DIN/DOUT VDD_CORE2 DQ00 DQ01 DQ02 DQ03 DQ04 DQ05 DQ06 DVDD1 R/W XI DGND2 TEST RESETB CLK CLK88 EQO RFI ANA_MONI1 ANA_MONI0 AD_MONI1 AD_MONI0 VDD_RD HPRDACO VSS_RD VSS_LD HPLDACO VDD_LD AVDD2 RDACO VCDAC LDACO AGND2 FLAG0 DVDD2 XO 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 80 79 78 77 76 75 74 73 72 71 70 69 54 53 52 51 49 46 45 44 68 67 66 65 64 63 62 61 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 43 42 41 47 48 50 60 59 58 57 55 56 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 20 D-NF007/NF0070 5-8. IC PIN FUNCTION DESCRIPTION Pin No. Pin name I/O Description 1 SEG0 O Not used (OPEN) 2 to 21 SEG1 to SEG20 O LCD segment output 22 LINEOUT_MUTE O Mute signal output 23 EE_SDA/REM_SDA I/O EEPROM data 24 EE_SCL O EEPROM clock 25 SYSREQ O Request output to IC1001 26 SYSBUSY O BUSY output to IC1001 27 IFACK I ACK input from IC1001 28 IFBUSY I BUS BUSY input from IC1001 29 CEL_CEX I Select model 30 SYSSEL O Master/Slave select signal output to IC1001 31 IFRST O Reset output to IC1001 32 IFRDY I IFRDY input from IC1001 33 GND – Ground terminal 34 TDI (IFCON) I Data for serial communications input 35 TDO (IFCON&VOL DATA) O Data for serial communications output 36 TCK (IFCON&VOL CLK) O Clock for serial communications output 37 VOL_EN O Volume enable output to IC901 38 LINE_DET I Not used (OPEN) 39 SUBSYQ I Sub code sync interruption input 40 HOLD I HOLD switch status detection input 41 OPEN/CLOSE I OPEN switch status detection input 42 TU_TEST I Tuner test terminal 43 K_PLAY I PLAY KEY input 44 K_TUNER I TUNER KEY input 45 (CHG_CLK) O Clock select phase match output 46 NC O Not used (OPEN) 47 DIN OUT I/O Command output , DSP status input, subcode Q input 48 MCK O Serial interface clock output 49 RW O DSP’s serial interface Read/Write signal output 50 BUSY I DSP’s auto sequencer status 51 FIFO O SDRAM initialize output 52 VDD – Power supply for CPU and I/O 53 XRESET O System reset output 54 IFMUTE I Phase match with IC1001 55 TU_CTL O Tuner power control output 56 HP_MUTE O Headphone IC mute ON/OFF control output 57 RESETB I Microcomputer reset terminal 58 TEST0 I Connect to GND 59 XIN75 I 75kHz clock input 60 XOUT75 O 75kHz clock output 61 GND – Ground terminal 62 XIN8M I 8MHz clock input 63 XOUT8M O 8MHz clock output (OPEN) 64 VDD – Power supply for CPU and I/O 65 DC_IN I DC IN voltage monitoring input • IC801 BU18704-S5 (SYSTEM CONTROLLER) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 21 D-NF007/NF0070 Pin No. Pin name I/O Description 66 BATT+ I Batt+ terminal voltage monitoring input 67 KEY1 I Key matrix detect input 68 KEY2 I Key matrix detect input 69 TEST I Test mode terminal 70 WREM I Wired remotecontroler key detection input 71 SEL_VERSION I Select version 72 NC I Connect to GND 73 TEST1 I Test mode terminal (not used) 74 P.OFF O Power OFF control output 75 MMUTE1 O Spindle motor drive mute output 76 MMUTE2 O Focus/Tracking drive mute output 77 to 80 COM1 to COM4 O LCD common output www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 22 D-NF007/NF0070 1 GND – Ground terminal 2 XIN I 8MHz clock input 3 XOUT O 8MHz clock output 4 TEST I Fixed at ground 5 VCPU – Power supply terminal 6 XTIN I 75kHz clock input 7 XTOUT O 75kHz clock output 8 RESET I Reset input from IC801 9 WSYSREQ I Request input from IC801 10 FM_H O AM/FM select signal output to PLL IC(IC001) 11 CK_CTL1 O CLOCK IC(IC471) control output 12 PLL_CE O Chip enable output to PLL IC(IC001) 13 TCK I Clock for serial communications input from IC801 14 TDO I Data for serial communications input from IC801 15 TDI O Data for serial communications input to IC801 16 SYSSEL I Master/Slave select signal input from IC801 17 SYSREQ I Request input from IC801 18 IFACK O ACK output to IC801 19 NC I/O Not used 20 NC O Not used 21 SYSBUSY I BUSY input from IC801 22 IFRDY O IFRDY signal output to IC801 23 SDA O Serial communications data output to EEPROM(IC802) 24 SCL O Serial communications clock output to EEPROM(IC802) 25 IFBUSY O BUS BUSY signal output to IC801 26 NC I/O Not used 27 IFMUTE O Phase match with IC801 28 (CHG_CLK) I Clock select phase match 29 AM_SEL I AM clock shift select signal input(fixed at ground in this set) 30 CK_CTL2 O Clock shift circuit control output Pin No. Pin name I/O Description • IC1001 TMP86C808DMG-6F65 (TUNER CONTROLLER) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 23 D-NF007/NF0070 SECTION 6 EXPLODED VIEWS NOTE: • -XX and -X mean standardized parts, so they may have some difference from the original one. • Items marked “*” are not stocked since they are seldom required for routine service. Some delay should be anticipated when ordering these items. • The mechanical parts with no reference number in the exploded views are not supplied. • Color Indication of Appearance Parts Example: KNOB, BALANCE (WHITE) . . . (RED) R R Parts of Color Cabinet’s Color • Accessories are given in the last of the electrical parts list. • Abbreviation 3AEP : UK model 8E19 : Philippines model AUS : Australian model CND : Canadian model E19 : Singapore model EE : East European model Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 1 2 5 4 3 7 6 8 9 9 10 11 17 12 14 20 15 16 18 19 13 Les composants identifiés par une marque 0 sont critiques pour la sécurité. Ne les remplacer que par une pièce portant le numéro spécifié. The components identified by mark 0 or dotted line with mark 0 are critical for safety. Replace only with part number specified. 1 2-638-196-01 BUTTON (B) (SILVER) 1 2-638-196-11 BUTTON (B) (WHITE) 1 2-638-196-21 BUTTON (B) (BLACK) 2 2-638-197-01 KNOB (HOLD) (SILVER) 2 2-638-197-11 KNOB (HOLD) (WHITE) 2 2-638-197-21 KNOB (HOLD) (BLACK) 3 2-596-449-01 TERMINAL (RELAY), BATTERY 4 2-638-934-01 BUTTON (A) (SILVER) 4 2-638-934-11 BUTTON (A) (BLACK) 4 2-638-934-31 BUTTON (A) (WHITE) 5 X-2103-447-1 CABINET (LOWER) (B) SUB ASSY (BLACK) 5 X-2103-449-1 CABINET (LOWER) (S) SUB ASSY (SILVER) 5 X-2103-450-1 CABINET (LOWER) (W) SUB ASSY (WHITE) 6 2-596-447-01 TERMINAL (+), BATTERY 7 2-596-448-01 TERMINAL (–), BATTERY 8 A-1143-674-A MAIN BOARD, COMPLETE (NF007: CND/NF0070) 8 A-1143-677-A MAIN BOARD, COMPLETE (NF007: AEP) 8 A-1143-680-A MAIN BOARD, COMPLETE (NF007: 3AEP, EE) 8 A-1143-683-A MAIN BOARD, COMPLETE (NF007: AUS) 8 A-1143-686-A MAIN BOARD, COMPLETE (NF007: E19, 8E19) 9 3-245-331-02 INSULATOR 010 A-1112-193-A OPTICAL PICK-UP CDM-3525A 11 X-2067-449-1 LID ASSY (B) (A), UPPER (BLACK) (NF007) 11 X-2067-451-1 LID ASSY (S), UPPER (SILVER) (NF007) 11 X-2067-452-1 LID ASSY (B) (L), UPPER (BLACK) (NF0070) 11 X-2067-802-1 LID ASSY (S) (L), UPPER (SILVER) (NF0070) 11 X-2102-352-1 LID ASSY (W), UPPER (WHITE) (NF007) 12 2-596-453-03 SPRING (UPPER LID) 13 2-660-036-01 CABINET (MIDDLE) (CND) 13 2-660-036-11 CABINET (MIDDLE) (EXCEPT CND) 14 2-596-454-03 LID, BATTERY CASE (WHITE) 14 2-596-454-13 LID, BATTERY CASE (SILVER, BLACK) 15 2-596-441-01 SPRING (OPEN) 16 2-638-194-01 KNOB (OPEN) (SILVER) 16 2-638-194-11 KNOB (OPEN) (WHITE) 16 2-638-194-21 KNOB (OPEN) (BLACK) 17 3-254-070-01 SCREW 18 2-659-212-01 CASE, SHIELD 19 2-661-945-01 SHEET (COIL) 20 2-662-461-01 SHEET (BATT) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 24 D-NF007/NF0070 SECTION 7 ELECTRICAL PARTS LIST Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark NOTE: • Due to standardization, replacements in the parts list may be different from the parts specified in the diagrams or the components used on the set. • -XX and -X mean standardized parts, so they may have some difference from the original one. • RESISTORS All resistors are in ohms. METAL: Metal-film resistor. METAL OXIDE: Metal oxide-film resistor. F: nonflammable • Items marked “*” are not stocked since they are seldom required for routine service. Some delay should be anticipated when ordering these items. • SEMICONDUCTORS In each case, u: µ, for example: uA... : µA... uPA... : µPA... uPB... : µPB... uPC... : µPC... uPD... : µPD... • CAPACITORS uF: µF • COILS uH: µH • Abbreviation 3AEP : UK model 8E19 : Philippines model AUS : Australian model C&SA : Central and South American model CND : Canadian model When indicating parts by reference number, please include the board. MAIN Les composants identifiés par une marque 0 sont critiques pour la sécurité. Ne les remplacer que par une pièce portant le numéro spécifié. The components identified by mark 0 or dotted line with mark 0 are critical for safety. Replace only with part number specified. A-1143-674-A MAIN BOARD, COMPLETE (NF007: CND/NF0070) A-1143-677-A MAIN BOARD, COMPLETE (NF007: AEP) A-1143-680-A MAIN BOARD, COMPLETE (NF007: 3AEP, EE) A-1143-683-A MAIN BOARD, COMPLETE (NF007: AUS) A-1143-686-A MAIN BOARD, COMPLETE (NF007: E19, 8E19) ********************* 2-596-447-01 TERMINAL (+), BATTERY 2-596-448-01 TERMINAL (–), BATTERY 2-659-212-01 CASE, SHIELD 2-661-945-01 SHEET (COIL) < CAPACITOR > C002 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V C003 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V C004 1-164-230-11 CERAMIC CHIP 220PF 5% 50V C005 1-164-156-11 CERAMIC CHIP 0.1uF 25V C006 1-162-910-11 CERAMIC CHIP 5PF 0.25PF 50V C008 1-164-230-11 CERAMIC CHIP 220PF 5% 50V C009 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C010 1-164-217-11 CERAMIC CHIP 150PF 5% 50V C011 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C012 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C013 1-126-513-11 ELECT 47uF 20% 6.3V C014 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V C016 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C017 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C018 1-162-910-11 CERAMIC CHIP 5PF 0.25PF 50V C019 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C020 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C021 1-164-217-11 CERAMIC CHIP 150PF 5% 50V C022 1-162-910-11 CERAMIC CHIP 5PF 0.25PF 50V C023 1-100-507-91 CERAMIC CHIP 4.7uF 20% 6.3V C024 1-164-230-11 CERAMIC CHIP 220PF 5% 50V C025 1-100-507-91 CERAMIC CHIP 4.7uF 20% 6.3V C026 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C027 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C028 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C029 1-162-962-11 CERAMIC CHIP 470PF 10% 50V C030 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C031 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C032 1-127-715-91 CERAMIC CHIP 0.22uF 10% 16V C033 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C034 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V C035 1-164-505-11 CERAMIC CHIP 2.2uF 16V C036 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C037 1-127-573-11 CERAMIC CHIP 1uF 10% 16V C038 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C039 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C040 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C041 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C042 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C043 1-162-917-11 CERAMIC CHIP 15PF 5% 50V C044 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C045 1-162-919-11 CERAMIC CHIP 22PF 5% 50V C046 1-100-507-91 CERAMIC CHIP 4.7uF 20% 6.3V C047 1-162-910-11 CERAMIC CHIP 5PF 0.25PF 50V C048 1-100-507-91 CERAMIC CHIP 4.7uF 20% 6.3V C049 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C050 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C101 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V C102 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C104 1-124-635-00 ELECT 220uF 20% 6.3V C105 1-165-884-91 CERAMIC CHIP 2.2uF 10% 6.3V C106 1-127-715-91 CERAMIC CHIP 0.22uF 10% 16V (AEP, 3AEP, EE) C108 1-162-962-11 CERAMIC CHIP 470PF 10% 50V C109 1-110-563-11 CERAMIC CHIP 0.068uF 10% 16V C110 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C201 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V C202 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C204 1-124-635-00 ELECT 220uF 20% 6.3V C205 1-165-884-91 CERAMIC CHIP 2.2uF 10% 6.3V C206 1-127-715-91 CERAMIC CHIP 0.22uF 10% 16V (AEP, 3AEP, EE) C208 1-162-962-11 CERAMIC CHIP 470PF 10% 50V C209 1-110-563-11 CERAMIC CHIP 0.068uF 10% 16V C210 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C301 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C303 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V C304 1-126-382-11 ELECT 100uF 20% 16V C305 1-126-513-11 ELECT 47uF 20% 6.3V C401 1-100-352-91 CERAMIC CHIP 1uF 20% 16V C402 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V C403 1-164-156-11 CERAMIC CHIP 0.1uF 25V C404 1-126-791-11 ELECT 10uF 20% 35V C405 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C406 1-164-156-11 CERAMIC CHIP 0.1uF 25V E19 : Singapore model EE : East European model Ver. 1.1 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 25 D-NF007/NF0070 MAIN C407 1-100-733-91 CERAMIC CHIP 10uF 20% 6.3V C408 1-126-382-11 ELECT 100uF 20% 16V C409 1-126-791-11 ELECT 10uF 20% 35V C410 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C411 1-162-960-11 CERAMIC CHIP 220PF 10% 50V C412 1-115-156-11 CERAMIC CHIP 1uF 10V C413 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V C416 1-162-923-11 CERAMIC CHIP 47PF 5% 50V C417 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C419 1-124-635-00 ELECT 220uF 20% 6.3V C420 1-124-635-00 ELECT 220uF 20% 6.3V C421 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V C450 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V C452 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V C453 1-164-315-11 CERAMIC CHIP 470PF 5% 50V C454 1-100-733-91 CERAMIC CHIP 10uF 20% 6.3V C470 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V C471 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C472 1-162-927-11 CERAMIC CHIP 100PF 5% 50V C473 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V C474 1-162-913-11 CERAMIC CHIP 8PF 0.5PF 50V C475 1-162-960-11 CERAMIC CHIP 220PF 10% 50V C476 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V C477 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V C478 1-164-315-11 CERAMIC CHIP 470PF 5% 50V C480 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V C481 1-162-923-11 CERAMIC CHIP 47PF 5% 50V C601 1-126-513-11 ELECT 47uF 20% 6.3V C602 1-126-513-11 ELECT 47uF 20% 6.3V C603 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C604 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C605 1-164-156-11 CERAMIC CHIP 0.1uF 25V C606 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C607 1-126-513-11 ELECT 47uF 20% 6.3V C609 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V C610 1-126-794-11 ELECT 4.7uF 20% 50V C611 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V C612 1-164-156-11 CERAMIC CHIP 0.1uF 25V C615 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V C618 1-162-962-11 CERAMIC CHIP 470PF 10% 50V C619 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C620 1-164-156-11 CERAMIC CHIP 0.1uF 25V C623 1-119-941-41 ELECT 470uF 20% 6.3V C624 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C625 1-125-838-11 CERAMIC CHIP 2.2uF 10% 6.3V C626 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V C627 1-100-507-91 CERAMIC CHIP 4.7uF 20% 6.3V C628 1-126-791-11 ELECT 10uF 20% 35V C629 1-165-884-91 CERAMIC CHIP 2.2uF 10% 6.3V C631 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C632 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V C633 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C634 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V C637 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C638 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V C640 1-100-507-91 CERAMIC CHIP 4.7uF 20% 6.3V C802 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C805 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C806 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C807 1-115-156-11 CERAMIC CHIP 1uF 10V C808 1-115-156-11 CERAMIC CHIP 1uF 10V C809 1-164-156-11 CERAMIC CHIP 0.1uF 25V C810 1-100-733-91 CERAMIC CHIP 10uF 20% 6.3V C811 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C812 1-162-962-11 CERAMIC CHIP 470PF 10% 50V C813 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V C814 1-162-962-11 CERAMIC CHIP 470PF 10% 50V C815 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C872 1-162-916-11 CERAMIC CHIP 12PF 5% 50V C874 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C875 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C876 1-162-919-11 CERAMIC CHIP 22PF 5% 50V C877 1-162-919-11 CERAMIC CHIP 22PF 5% 50V C880 1-162-962-11 CERAMIC CHIP 470PF 10% 50V C881 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C882 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C901 1-100-507-91 CERAMIC CHIP 4.7uF 20% 6.3V C902 1-100-507-91 CERAMIC CHIP 4.7uF 20% 6.3V C903 1-100-507-91 CERAMIC CHIP 4.7uF 20% 6.3V C905 1-115-156-11 CERAMIC CHIP 1uF 10V C906 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V C907 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V C908 1-216-864-11 SHORT CHIP 0 C909 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V C910 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C1001 1-100-733-91 CERAMIC CHIP 10uF 20% 6.3V < COMPOSITION CIRCUIT BLOCK > CB414 1-112-557-11 CERAMIC CHIP 0.022uF 20% 16V < FILTER > CF001 1-760-235-11 FILTER, CERAMIC (10.7MHz) CF002 1-795-323-11 FILTER, CERAMIC (459kHz) CF003 1-813-422-11 DISCRIMINATOR, CERAMIC (10.7MHz) < CONNECTOR > CN501 1-774-975-51 CONNECTOR, FFC/FPC 16P < TRIMMER > CT001 1-141-373-11 CAP, TRIMMER 10PF (AM TRACKING ADJUSTMENT) < DIODE > D001 6-500-169-01 DIODE KV1610STL-G@1-2 D002 8-719-076-23 DIODE HVC202B TRU-E D003 8-719-076-23 DIODE HVC202B TRU-E D004 8-719-988-61 DIODE 1SS355TE-17 D101 8-719-083-04 DIODE RSB6.8STE61 D201 8-719-083-04 DIODE RSB6.8STE61 D401 8-719-069-56 DIODE UDZSTE-176.2B D402 8-719-081-34 DIODE RB160M-30TR D403 8-719-081-34 DIODE RB160M-30TR D404 8-719-083-82 DIODE UDZS-TE17-12B D420 8-719-083-82 DIODE UDZS-TE17-12B www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 26 D-NF007/NF0070 MAIN D871 6-500-335-01 DIODE MC2838-T112-1 D872 6-500-335-01 DIODE MC2838-T112-1 < FUSE > 0F401 1-576-415-21 FUSE 2A 32V 0F402 1-576-406-21 FUSE 1.4A 32V < FERRITE BEAD > FB101 1-414-760-21 FERRITE, EMI (SMD) (1608) FB201 1-414-760-21 FERRITE, EMI (SMD) (1608) FB301 1-414-813-11 FERRITE, EMI (SMD) (2012) FB305 1-414-760-21 FERRITE, EMI (SMD) (1608) FB401 1-216-295-91 SHORT CHIP 0 FB402 1-414-813-11 FERRITE, EMI (SMD) (2012) FB403 1-412-028-11 INDUCTOR 4.7uH FB404 1-412-028-11 INDUCTOR 4.7uH FB601 1-216-864-11 SHORT CHIP 0 FB603 1-216-864-11 SHORT CHIP 0 FB604 1-414-760-21 FERRITE, EMI (SMD) (1608) FB605 1-414-760-21 FERRITE, EMI (SMD) (1608) FB606 1-414-760-21 FERRITE, EMI (SMD) (1608) FB901 1-216-864-11 SHORT CHIP 0 < FLUORESCENT INDICATOR > FL001 1-236-711-21 FILTER, BAND PASS < IC > IC001 6-706-435-01 IC TB2132FNG IC301 8-759-588-61 IC BH3544F-FE2 IC401 6-704-047-01 IC BH6575FV-E2 IC471 6-708-327-01 IC TC7WH240FK IC601 6-709-383-01 IC BU9541JKV IC602 6-708-188-01 IC M12L16161A-7T (G) IC603 6-705-807-01 IC BH15FB1WG IC801 6-806-078-02 IC BU18704-S6 IC802 6-704-001-01 IC BR24L02F-WE2 IC901 6-703-615-01 IC SM6451BT-G-E2 IC1001 6-806-058-02 IC TMP86C808DMG-6F65 IC1002 8-759-386-68 IC BU4S584-TR < JACK > J301 1-819-363-11 JACK, HEADPHONE (REMOTE i) J401 1-819-364-11 JACK, DC (POLARITY UNIFIED TYPE) (DC IN 4.5V) < COIL > L001 1-457-103-11 COIL, FERRITE-ROD ANTENNA (AM) L002 1-414-228-11 INDUCTOR, FERRITE BEAD L003 1-457-101-11 COIL, AIR-CORE (FM TRACKING ADJUSTMENT) L004 1-457-102-11 COIL, AIR-CORE (FM FREQUENCY COVERAGE ADJUSTMENT) L005 1-414-233-22 INDUCTOR, FERRITE BEAD L006 1-414-233-22 INDUCTOR, FERRITE BEAD L007 1-216-864-11 SHORT CHIP 0 L008 1-414-228-11 INDUCTOR, FERRITE BEAD L402 1-457-096-11 INDUCTOR 165uH L403 1-469-967-21 INDUCTOR 10uH L406 1-400-145-21 INDUCTOR 47uH L407 1-400-145-21 INDUCTOR 47uH L450 1-400-548-11 INDUCTOR 1mH < TRANSISTOR > Q001 8-729-028-74 TRANSISTOR DTA114TUA-T106 Q002 8-729-044-37 TRANSISTOR 2SK3019TL Q003 8-729-602-21 TRANSISTOR 2SC4154-F Q101 6-551-395-01 TRANSISTOR UMH8N-TR Q102 6-550-375-01 TRANSISTOR UMD2N-TR Q401 8-729-903-53 TRANSISTOR 2SB1132-T100-Q Q402 6-551-395-01 TRANSISTOR UMH8N-TR Q403 6-550-364-01 TRANSISTOR 2SD2652T106 Q404 6-550-364-01 TRANSISTOR 2SD2652T106 Q471 8-729-028-74 TRANSISTOR DTA114TUA-T106 Q472 8-729-051-23 TRANSISTOR 2SA2018TL Q473 8-729-028-97 TRANSISTOR DTC114TUA-T106 Q474 8-729-038-38 TRANSISTOR RT1N144M-TP-1 Q475 8-729-028-97 TRANSISTOR DTC114TUA-T106 Q476 8-729-038-38 TRANSISTOR RT1N144M-TP-1 Q477 8-729-028-74 TRANSISTOR DTA114TUA-T106 Q479 8-729-051-23 TRANSISTOR 2SA2018TL Q480 8-729-028-97 TRANSISTOR DTC114TUA-T106 Q601 8-729-602-36 TRANSISTOR 2SA1602-F Q602 8-729-028-97 TRANSISTOR DTC114TUA-T106 Q603 8-729-051-23 TRANSISTOR 2SA2018TL Q803 8-729-905-40 TRANSISTOR 2SC4081T106 Q804 8-729-905-40 TRANSISTOR 2SC4081T106 < RESISTOR > R001 1-216-853-11 METAL CHIP 470K 5% 1/10W R002 1-216-821-11 METAL CHIP 1K 5% 1/10W R004 1-216-853-11 METAL CHIP 470K 5% 1/10W R005 1-216-853-11 METAL CHIP 470K 5% 1/10W R006 1-216-801-11 METAL CHIP 22 5% 1/10W R007 1-216-821-11 METAL CHIP 1K 5% 1/10W (NF007:CND/NF0070) R007 1-216-825-11 METAL CHIP 2.2K 5% 1/10W (NF007:EXCEPT CND) R008 1-216-817-11 METAL CHIP 470 5% 1/10W R009 1-216-833-11 METAL CHIP 10K 5% 1/10W R011 1-216-813-11 METAL CHIP 220 5% 1/10W R012 1-216-813-11 METAL CHIP 220 5% 1/10W R013 1-216-864-11 SHORT CHIP 0 R014 1-216-835-11 METAL CHIP 15K 5% 1/10W R015 1-216-813-11 METAL CHIP 220 5% 1/10W R016 1-216-841-11 METAL CHIP 47K 5% 1/10W R017 1-216-827-11 METAL CHIP 3.3K 5% 1/10W R018 1-216-864-11 SHORT CHIP 0 R019 1-216-833-11 METAL CHIP 10K 5% 1/10W R020 1-216-833-11 METAL CHIP 10K 5% 1/10W R021 1-216-821-11 METAL CHIP 1K 5% 1/10W R022 1-216-845-11 METAL CHIP 100K 5% 1/10W R023 1-216-813-11 METAL CHIP 220 5% 1/10W R024 1-216-841-11 METAL CHIP 47K 5% 1/10W R026 1-216-813-11 METAL CHIP 220 5% 1/10W R027 1-216-801-11 METAL CHIP 22 5% 1/10W R030 1-216-864-11 SHORT CHIP 0 R031 1-216-864-11 SHORT CHIP 0 Ver. 1.1 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 27 D-NF007/NF0070 MAIN R036 1-216-864-11 SHORT CHIP 0 R101 1-216-797-11 METAL CHIP 10 5% 1/10W R102 1-216-789-11 METAL CHIP 2.2 5% 1/10W (AEP, 3AEP, EE) R103 1-216-813-11 METAL CHIP 220 5% 1/10W R104 1-216-857-11 METAL CHIP 1M 5% 1/10W R111 1-216-797-11 METAL CHIP 10 5% 1/10W R201 1-216-797-11 METAL CHIP 10 5% 1/10W R202 1-216-789-11 METAL CHIP 2.2 5% 1/10W (AEP, 3AEP, EE) R203 1-216-813-11 METAL CHIP 220 5% 1/10W R204 1-216-857-11 METAL CHIP 1M 5% 1/10W R211 1-216-797-11 METAL CHIP 10 5% 1/10W R303 1-216-857-11 METAL CHIP 1M 5% 1/10W R304 1-216-864-11 SHORT CHIP 0 R305 1-216-849-11 METAL CHIP 220K 5% 1/10W R307 1-216-864-11 SHORT CHIP 0 R308 1-216-864-11 SHORT CHIP 0 R401 1-216-845-11 METAL CHIP 100K 5% 1/10W R402 1-216-837-11 METAL CHIP 22K 5% 1/10W R403 1-216-821-11 METAL CHIP 1K 5% 1/10W R404 1-216-809-11 METAL CHIP 100 5% 1/10W R405 1-218-873-11 METAL CHIP 12K 0.5% 1/10W R406 1-216-833-11 METAL CHIP 10K 5% 1/10W R407 1-218-881-11 METAL CHIP 27K 0.5% 1/10W R408 1-414-554-21 FERRITE, EMI (SMD) (1608) R409 1-216-864-11 SHORT CHIP 0 R410 1-245-927-21 METAL CHIP 0.22 1% 1/5W R411 1-216-853-11 METAL CHIP 470K 5% 1/10W R412 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R414 1-216-797-11 METAL CHIP 10 5% 1/10W R415 1-216-821-11 METAL CHIP 1K 5% 1/10W R416 1-216-837-11 METAL CHIP 22K 5% 1/10W R417 1-216-845-11 METAL CHIP 100K 5% 1/10W R418 1-216-841-11 METAL CHIP 47K 5% 1/10W R419 1-216-837-11 METAL CHIP 22K 5% 1/10W R471 1-216-845-11 METAL CHIP 100K 5% 1/10W R472 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R473 1-216-833-11 METAL CHIP 10K 5% 1/10W R474 1-469-179-21 INDUCTOR, FERRITE BEAD R475 1-216-845-11 METAL CHIP 100K 5% 1/10W R476 1-216-835-11 METAL CHIP 15K 5% 1/10W R477 1-216-853-11 METAL CHIP 470K 5% 1/10W R478 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R480 1-216-845-11 METAL CHIP 100K 5% 1/10W R481 1-216-845-11 METAL CHIP 100K 5% 1/10W R482 1-216-825-11 METAL CHIP 2.2K 5% 1/10W R483 1-216-797-11 METAL CHIP 10 5% 1/10W R484 1-216-841-11 METAL CHIP 47K 5% 1/10W R485 1-216-864-11 SHORT CHIP 0 R601 1-216-833-11 METAL CHIP 10K 5% 1/10W R602 1-216-813-11 METAL CHIP 220 5% 1/10W R603 1-216-793-11 METAL CHIP 4.7 5% 1/10W R604 1-216-845-11 METAL CHIP 100K 5% 1/10W R605 1-216-864-11 SHORT CHIP 0 R606 1-216-849-11 METAL CHIP 220K 5% 1/10W R607 1-216-833-11 METAL CHIP 10K 5% 1/10W R608 1-216-833-11 METAL CHIP 10K 5% 1/10W R613 1-216-843-11 METAL CHIP 68K 5% 1/10W R614 1-216-817-11 METAL CHIP 470 5% 1/10W R615 1-216-843-11 METAL CHIP 68K 5% 1/10W R617 1-216-809-11 METAL CHIP 100 5% 1/10W R618 1-216-857-11 METAL CHIP 1M 5% 1/10W R619 1-216-845-11 METAL CHIP 100K 5% 1/10W R620 1-216-833-11 METAL CHIP 10K 5% 1/10W R621 1-216-864-11 SHORT CHIP 0 R622 1-216-813-11 METAL CHIP 220 5% 1/10W R623 1-216-864-11 SHORT CHIP 0 R624 1-216-845-11 METAL CHIP 100K 5% 1/10W R626 1-216-813-11 METAL CHIP 220 5% 1/10W R629 1-216-864-11 SHORT CHIP 0 R630 1-216-864-11 SHORT CHIP 0 R672 1-216-864-11 SHORT CHIP 0 R673 1-216-845-11 METAL CHIP 100K 5% 1/10W R674 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R675 1-216-789-11 METAL CHIP 2.2 5% 1/10W R804 1-216-864-11 SHORT CHIP 0 (EXCEPT AEP) R808 1-216-845-11 METAL CHIP 100K 5% 1/10W (AEP) R810 1-216-857-11 METAL CHIP 1M 5% 1/10W R811 1-216-845-11 METAL CHIP 100K 5% 1/10W R812 1-216-845-11 METAL CHIP 100K 5% 1/10W R817 1-216-833-11 METAL CHIP 10K 5% 1/10W R820 1-216-861-11 METAL CHIP 2.2M 5% 1/10W R821 1-216-845-11 METAL CHIP 100K 5% 1/10W R823 1-216-821-11 METAL CHIP 1K 5% 1/10W R824 1-216-825-11 METAL CHIP 2.2K 5% 1/10W R826 1-414-760-21 FERRITE, EMI (SMD) (1608) R828 1-216-825-11 METAL CHIP 2.2K 5% 1/10W R829 1-216-845-11 METAL CHIP 100K 5% 1/10W R835 1-414-760-21 FERRITE, EMI (SMD) (1608) R843 1-216-833-11 METAL CHIP 10K 5% 1/10W R844 1-216-833-11 METAL CHIP 10K 5% 1/10W R845 1-216-833-11 METAL CHIP 10K 5% 1/10W R846 1-216-833-11 METAL CHIP 10K 5% 1/10W R847 1-216-825-11 METAL CHIP 2.2K 5% 1/10W R848 1-216-825-11 METAL CHIP 2.2K 5% 1/10W R849 1-216-825-11 METAL CHIP 2.2K 5% 1/10W R850 1-216-864-11 SHORT CHIP 0 R851 1-216-837-11 METAL CHIP 22K 5% 1/10W R852 1-216-825-11 METAL CHIP 2.2K 5% 1/10W R853 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R854 1-216-837-11 METAL CHIP 22K 5% 1/10W R856 1-216-829-11 METAL CHIP 4.7K 5% 1/10W R871 1-216-845-11 METAL CHIP 100K 5% 1/10W (AEP, 3AEP, EE) R871 1-216-849-11 METAL CHIP 220K 5% 1/10W (E19, 8E19, AUS) R872 1-216-841-11 METAL CHIP 47K 5% 1/10W (NF007:EXCEPT CND) R872 1-216-849-11 METAL CHIP 220K 5% 1/10W (NF007:CND/NF0070) R873 1-216-825-11 METAL CHIP 2.2K 5% 1/10W R874 1-216-845-11 METAL CHIP 100K 5% 1/10W R875 1-216-821-11 METAL CHIP 1K 5% 1/10W R876 1-216-841-11 METAL CHIP 47K 5% 1/10W www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 28 D-NF007/NF0070 R877 1-216-841-11 METAL CHIP 47K 5% 1/10W R879 1-216-857-11 METAL CHIP 1M 5% 1/10W R880 1-216-817-11 METAL CHIP 470 5% 1/10W R881 1-216-817-11 METAL CHIP 470 5% 1/10W R882 1-216-864-11 SHORT CHIP 0 R901 1-216-797-11 METAL CHIP 10 5% 1/10W R902 1-216-797-11 METAL CHIP 10 5% 1/10W R904 1-216-813-11 METAL CHIP 220 5% 1/10W R905 1-216-813-11 METAL CHIP 220 5% 1/10W R906 1-216-813-11 METAL CHIP 220 5% 1/10W R1001 1-414-760-21 FERRITE, EMI (SMD) (1608) R1003 1-216-864-11 SHORT CHIP 0 R1004 1-216-864-11 SHORT CHIP 0 R1005 1-216-837-11 METAL CHIP 22K 5% 1/10W R1008 1-216-821-11 METAL CHIP 1K 5% 1/10W R1009 1-216-821-11 METAL CHIP 1K 5% 1/10W R1010 1-216-864-11 SHORT CHIP 0 R1011 1-216-864-11 SHORT CHIP 0 R1012 1-216-864-11 SHORT CHIP 0 R1013 1-216-864-11 SHORT CHIP 0 R1014 1-216-864-11 SHORT CHIP 0 R1015 1-216-864-11 SHORT CHIP 0 R1016 1-216-864-11 SHORT CHIP 0 R1017 1-216-837-11 METAL CHIP 22K 5% 1/10W R1018 1-216-857-11 METAL CHIP 1M 5% 1/10W R1019 1-216-864-11 SHORT CHIP 0 < COMPOSITION CIRCUIT BLOCK > RB301 1-233-787-11 RES, NETWORK 1.0K (1608) RB302 1-236-420-11 RES, NETWORK (1608) 4.7K RB303 1-233-679-91 RES, NETWORK (1608) 470 RB304 1-233-679-91 RES, NETWORK (1608) 470 RB305 1-233-793-91 RES, NETWORK 220K (1608) RB620 1-233-789-11 RES, NETWORK 10K (1608) RB806 1-233-791-91 RES, NETWORK 47K (1608) RB901 1-233-796-11 RES, NETWORK (1608) RB902 1-236-420-11 RES, NETWORK (1608) 4.7K < VARIABLE RESISTOR > RV471 1-227-410-21 RES, ADJ, CERMET 10K (CLOCK SHIFT ADJUSTMENT) < SWITCH > S801 1-786-865-11 SWITCH, KEYBOARD (u , ENTER) S802 1-786-865-11 SWITCH, KEYBOARD (> , +, TUNE+) S803 1-786-865-11 SWITCH, KEYBOARD (., –, TUNE–) S804 1-786-865-11 SWITCH, KEYBOARD (VOL+) S805 1-786-865-11 SWITCH, KEYBOARD (VOL–) S806 1-786-865-11 SWITCH, KEYBOARD (GROUP) S807 1-786-865-11 SWITCH, KEYBOARD (x , RADIO OFF) S808 1-786-865-11 SWITCH, KEYBOARD (SOUND/AVLS) S809 1-786-865-11 SWITCH, KEYBOARD (P MODE/ F) S811 1-570-953-11 SWITCH, PUSH (1 KEY) (OPEN) S812 1-786-864-11 SWITCH, SLIDE (HOLD) S871 1-786-865-11 SWITCH, KEYBOARD (RADIO ON, BAND) < TRANSFORMER > T001 1-456-985-11 COIL, AM OSC (AM TRACKING ADJUSTMENT) T002 1-443-490-11 TRANSFORMER, IF (AM IFT) T003 1-443-599-11 TRANSFORMER, DC-DC CONVERTER < VARISTOR > VDR418 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V VDR802 1-801-923-11 VARISTOR, CHIP (1608) < VIBRATOR > X001 1-795-926-11 VIBRATOR, CRYSTAL (75kHz) X601 1-813-590-11 VIBRATOR, CERAMIC (16.9344MHz) X801 1-795-926-11 VIBRATOR, CRYSTAL (75kHz) X802 1-813-722-11 VIBRATOR, CERAMIC (8MHz) ************************************************************* MISCELLANEOUS ************** 010 A-1112-193-A OPTICAL PICK-UP CDM-3525A ************************************************************* ACCESSORIES ************ 0 1-477-661-12 ADAPTOR, AC (AC-ET455K) (C&SA, MX) 0 1-477-662-11 ADAPTOR, AC (AC-ET455K)(AEP, EE, E19, 8E19) 0 1-477-664-12 ADAPTOR, AC (AC-ET455K) (AUS) 1-542-640-11 HEADPHONE (BLACK) (NF007: E19, 8E19, AUS) 1-542-640-21 HEADPHONE (SILVER) (NF007: E19, 8E19, AUS) 1-542-673-11 HEADPHONE (BLACK) (NF007: AEP, 3AEP, EE/NF0070) 1-542-673-21 HEADPHONE (SILVER, WHITE) (NF007: CND/NF0070) 2-649-856-11 MANUAL, INSTRUCTION (ENGLISH, FRENCH, SPANISH, GERMAN) (AEP, 3AEP) 2-649-856-21 MANUAL, INSTRUCTION (FINNISH, ITALIAN, DUTCH, PORTUGUESE, SWEDISH) (AEP) 2-649-856-31 MANUAL, INSTRUCTION (ENGLISH, CZECH, HUNGARIAN, POLISH)(EE) 2-649-856-41 MANUAL, INSTRUCTION (RUSSIAN, SLOVAKIAN) (EE) 2-649-856-51 MANUAL, INSTRUCTION (ENGLISH) (E19, 8E19, AUS, C&SA) 2-649-856-61 MANUAL, INSTRUCTION (SPANISH) (NF0070) 2-649-856-71 MANUAL, INSTRUCTION (PORTUGUESE) (C&SA) 2-649-856-81 MANUAL, INSTRUCTION (SIMPLIFIED CHINESE) (NF007: E19) 2-649-856-91 MANUAL, INSTRUCTION (ENGLISH, FRENCH) (CND) MAIN Ver. 1.1 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 29 D-NF007/NF0070 MEMO www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com D-NF007/NF0070 REVISION HISTORY Clicking the version allows you to jump to the revised page. Also, clicking the version at the upper right on the revised page allows you to jump to the next revised page. Ver. Date Description of Revision 1.0 2005.09 New 1.1 2005.11 Value change for FM F.cover adjustment and RF level. Addition of lead wire for main board. Part No. change of IC601 and IC801. Renewal of accessories parts list. (SPM-05193) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com
