D-NE10 US Model Canadian Model AEP Model UK Model E Model Australian Model Chinese Model Tourist Model SERVICE MANUAL PORTABLE CD PLAYER Sony Corporation Personal Audio Company Published by Sony Engineering Corporation 9-961-304-03 2004C16-1 © 2004.03 SPECIFICATIONS Ver 1.2 2004.03 Model Name Using Similar Mechanism NEW CD Mechanism Type CDM-3325ER2 Optical Pick-up Name DAX-25E — Continued on next page — System Compact disc digital audio system Laser diode properties Material: GaAlAs Wavelength: λ = 770 - 800 nm Emission duration: Continuous Laser output: Less than 44.6 µW (This output is the value measured at a distance of 200 mm from the objective lens surface on the optical pick-up block with 7 mm aperture.) D-A conversion 1-bit quartz time-axis control Frequency response 20 - 20 000 Hz +1 –2 dB (measured by JEITA) Output (at 3 V input level) Line output (stereo minijack) Output level 0.7 V rms at 47 kΩ Recommended load impedance over 10 kΩ Headphones (stereo minijack) Approx. 5 mW + Approx. 5 mW at 16 Ω (Approx. 1.5 mW + Approx. 1.5 mW at 16 Ω )* *For the customers in Europe Optical digital output (optical output connector) Output level: –21 - –15 dBm Wavelength: 630 - 690 nm at peak level Power requirements • Sony NH-14WM rechargeable battery: 1.2 V DC × 1 • LR6 (size AA) battery: 1.5 V DC × 1 • AC power adaptor (DC IN 3 V jack): 220 V, 50 Hz (Model for China) 120 120 V, 60 Hz (Models for US, Canadian and Taiwan) 230 V, 50 Hz (Models for UK and Hong Kong) 100-240 V, 50 Hz (Models for AEP, Tourist, E18, Korean and East Europe) V, 60 Hz (Model for Me Battery life*1 (approx. hours) When you use the CD player on a flat and stable surface. When LIGHT mode and SOUND mode are set to “OFF.” Playing time varies depending on how the CD player is used. When using one NH-14WM (charged for about 5 hours*2) G-PROTECTION “G-PRO 1” “G-PRO 2” Audio CD 20 20 ATRAC CD*3 35 35 MP3 CD*4 28 28 When using external battery case (one alkaline battery*5) G-PROTECTION “G-PRO 1” “G-PRO 2” Audio CD 30 30 ATRAC CD*3 50 50 MP3 CD*4 40 40 When using one NH-14WM and external battery case (one alkaline battery*5) G-PROTECTION “G-PRO 1” “G-PRO 2” Audio CD 50 50 ATRAC CD*3 85 85 MP3 CD*4 70 70 220-240 V AC 50/60 Hz (Model for Saudi Arabia) Manufactured under license from Dolby Laboratories Licensing Corporation. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 2 D-NE10 TABLE OF CONTENTS 1. SERVICING NOTE ·························································· 3 2. GENERAL ·········································································· 5 3. DISASSEMBLY ································································ 6 3-1. UPPER LID (SUB) ASSY ············································ 7 3-2. LIGHT GUIDE LENS··················································· 8 3-3. CABINET (INNER) ······················································ 8 3-4. MAIN BOARD, CD MECHANISM DECK (CDM-3325ER2) ··············· 9 3-5. TURN TABLE MOTOR ASSY (M901), SLED MOTOR ASSY (M902), OPTICAL PICK-UP (DAX-25E)································ 10 4. ELECTRICAL CHECKING ········································· 11 5. DIAGRAMS ······································································ 12 5-1. BLOCK DIAGRAM – MAIN SECTION -1 – ·············································· 13 – MAIN SECTION -2 – ·············································· 14 – POWER SECTION – ··············································· 15 5-2. PRINTED WIRING BOARDS – MAIN BOARD (SIDE A) – ···································· 16 5-3. PRINTED WIRING BOARDS – MAIN BOARD (SIDE B) – ···································· 17 5-4. SCHEMATIC DIAGRAMS – MAIN BOARD (1/4) – ············································ 18 5-5. SCHEMATIC DIAGRAMS – MAIN BOARD (2/4) – ············································· 19 5-6. SCHEMATIC DIAGRAMS – MAIN BOARD (3/4) – ············································ 20 5-7. SCHEMATIC DIAGRAMS – MAIN BOARD (4/4) – ············································ 21 5-8. IC PIN FUNCTION DESCRIPTIONS ······················· 23 6. EXPLODED VIEWS ······················································ 28 7. ELECTRICAL PARTS LIST ······································· 31 Unleaded solder Boards requiring use of unleaded solder are printed with the lead- free mark (LF) indicating the solder contains no lead. (Caution: Some printed circuit boards may not come printed with the lead free mark due to their particular size.) : LEAD FREE MARK Unleaded solder has the following characteristics. • Unleaded solder melts at a temperature about 40°C higher than ordinary solder. Ordinary soldering irons can be used but the iron tip has to be applied to the solder joint for a slightly longer time. Soldering irons using a temperature regulator should be set to about 350°C. Caution: The printed pattern (copper foil) may peel away if the heated tip is applied for too long, so be careful! • Strong viscosity Unleaded solder is more viscous (sticky, less prone to flow) than ordinary solder so use caution not to let solder bridges occur such as on IC pins, etc. • Usable with ordinary solder It is best to use only unleaded solder but unleaded solder may also be added to ordinary solder. Flexible Circuit Board Repairing • Keep the temperature of the soldering iron around 270 ˚C dur- ing repairing. • Do not touch the soldering iron on the same conductor of the circuit board (within 3 times). • Be careful not to apply force on the conductor when soldering or unsoldering. Notes on chip component replacement • Never reuse a disconnected chip component. • Notice that the minus side of a tantalum capacitor may be dam- aged by heat. This appliance is classified as a CLASS 1 LASER product. The CLASS 1 LASER PRODUCT MARKING is located on the rear exterior. CAUTION Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure. On AC power adaptor • Use only the AC power adaptor supplied or recommeded in “Accessories (supplied/ optional).” Do not use any other AC power adaptor. It may cause a malfunction. Polarity of the plug *1 Measured value by the standard of JEITA (Japan Electronics and Information Technology Industries Association) *2 Charging time varies depending on how the rechargeable battery is used. *3 Recorded at 48 kbps *4 Recorded at 128 kbps *5 When using Sony alkaline battery LR6 (SG) (produced in Japan) Supplied accessories AC power adaptor (1) Rechar geable battery (1) Battery carrying case (1) Headphones/earphones (1) Remote control (1) Charging stand (1) Carrying pouch (1) External battery case (1) CD-ROM* (SonicStage Simple Burner) (1) User’s guide for SonicStage Simple Burner (1) Operating temperature 5°C - 35°C (41°F - 95°F) Dimensions (w/h/d) (excluding projecting parts and controls) Approx. 127 × 17.7 × 132.7 mm (5 × 23⁄32 × 5 1⁄4 in.) Mass (excluding accessories) Approx. 148 g (5.3 oz.) US and foreign patents licensed from Dolby Laboratories. Design and specifications are subject to change without notice. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 3 D-NE10 SECTION 1 SERVICING NOTE The laser diode in the optical pick-up block may suffer electrostatic breakdown because of the potential difference generated by the charged electrostatic load, etc. on clothing and the human body. During repair, pay attention to electrostatic breakdown and also use the procedure in the printed matter which is included in the repair parts. The flexible board is easily damaged and should be handled with care. NOTES ON LASER DIODE EMISSION CHECK The laser beam on this model is concentrated so as to be focused on the disc reflective surface by the objective lens in the optical pick- up block. Therefore, when checking the laser diode emission, observe from more than 30 cm away from the objective lens. BEFORE REPLACING THE OPTICAL PICK-UP BLOCK Please be sure to check thoroughly the parameters as par the “Optical Pick-Up Block Checking Procedures” (Part No.: 9-960-027-11) issued separately before replacing the optical pick-up block. Note and specifications required to check are given below. • FOK output: IC601 yg pin When checking FOK, remove the lead wire to disc motor. • RF signal P-to-P value: 0.45 to 0.65 Vp-p LASER DIODE AND FOCUS SEARCH OPERATION CHECK During normal operation of the equipment, emission of the laser diode is prohibited unless the upper lid is closed while turning ON the S812. The following checking method for the laser diode is operable. • Method: Emission of the laser diode is visually checked. 1. Remove the upper lid. 2. With a disc not set, turn on the S812 with a screwdriver having a thin tip as shown in Fig.1. 3. Press the u button. 4. Observing the objective lens, check that the laser diode emits light. When the laser diode does not emit light, automatic power control circuit or optical pickup is faulty. In this operation, the objective lens will move up and down 4 times along with inward motion for the focus search. NOTES ON HANDLING THE OPTICAL PICK-UP BLOCK OR BASE UNIT SAFETY-RELATED COMPONENT WARNING!! COMPONENTS IDENTIFIED BY MARK 0 OR DOTTED LINE WITH MARK 0 ON THE SCHEMATIC DIAGRAMS AND IN THE PARTS LIST ARE CRITICAL TO SAFE OPERATION. REPLACE THESE COMPONENTS WITH SONY PARTS WHOSE PART NUMBERS APPEAR AS SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUBLISHED BY SONY. ATTENTION AU COMPOSANT AYANT RAPPORT À LA SÉCURITÉ! LES COMPOSANTS IDENTIFÉS PAR UNE MARQUE 0 SUR LES DIAGRAMMES SCHÉMATIQUES ET LA LISTE DES PIÈCES SONT CRITIQUES POUR LA SÉCURITÉ DE FONCTIONNEMENT. NE REMPLACER CES COMPOSANTS QUE PAR DES PIÈSES SONY DONT LES NUMÉROS SONT DONNÉS DANS CE MANUEL OU DANS LES SUPPÉMENTS PUBLIÉS PAR SONY. Fig. 1 Method to push the S812 S812 IC601 FOK output ygpin MAIN BOARD (SIDE B) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 4 D-NE10 SERVICE MODE The following confirmation can be performed when the Service Mode is set. 1. How to set the Service Mode. To set the Service Mode, the following method is available. 1) Confirm the set is not powered on. 2) Confirm the following settings. OPEN/CLOSE detect switch (S812) ........ OFF Solder Land (SL812) ................................ OPEN [HOLD] switch (S802)............................... OFF 3) Short the solder land SL805 (TEST) on the MAIN board. 4) Turn on the main power. 2. Operation when the Service Mode is set. When the Service Mode becomes active, following messages are displayed onthe remote control LCD. 1) Turn off the power. 2) Open the solder land SL805 (TEST) on the MAIN board. Note : The solder should be removed clean. VP094P: VP098C: Microcomputer version display or SL812 (OPEN) S812 SL805 (TEST) MAIN BOARD (SIDE B) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 5 D-NE10 SECTION 2 GENERAL This section is extracted from instruction manual. 1 9 8 q; 2 3 4 5 6 7 Locating the controls CD player (rear) For details, see the pages in parentheses. 1 VOL (volume) +*1/– buttons (15) 2 u*1 (play/pause) button (14, 15) 3 x (stop)/CHG (charge) button (15, 29) 4 ./> (AMS*2/search) buttons (15) 5 (group) +/– buttons (15, 20) 6 Terminals for the charging stand/external battery case (14, 29, 30) 7 OPEN switch (14, 28) Squeeze the switch from both sides. 8 HOLD switch (23) Slide the switch in the direction of the arrow to disable the buttons on the CD player. 9 OPERATION lamp (front) (14, 23, 24, 29) Color of the lamp changes according to the type of music source being played. Red: Audio CD, Green: ATRAC3plus/ ATRAC3 file, Orange: MP3 file For some time after the CD is inserted, the lamp lights up in red, orange and green in turn. This lamp also functions as the HOLD lamp and the CHG (charge) lamp. q; i (headphones)/LINE OUT (OPTICAL) jack (14, 26) Switch the function of the jack, using the menu. *1 The button has a tactile dot. *2 Automatic Music Sensor 1 2 3 4 5 6 7 8 9 q; Remote control For details, see the pages in parentheses. 1 VOL (volume) +/– control (15, 21, 23) Turn to adjust the volume. 2 x (stop) button (15, 22, 23, 32) 3 Jog lever (. u/ENT >) (15, 18 - 26) u (play/pause)/ENT (enter): Press during stop to start play, and press during play to pause play. When selecting menu items, press to enter the selection. Flick toward . or >: AMS, rewind, fast forward 4 Display (13, 16) 5 (group) +/– buttons (15, 20) 6 Clip (13) 7 HOLD switch (23) Slide the switch in the direction of the arrow (a yellow mark appears) to disable the buttons on the remote control. 8 DISPLAY button (22 - 26, 32) 9 P MODE/ button (17 - 20) q; SOUND button (21) Note Use only the supplied remote control. You cannot operate this CD player with the remote control supplied with other CD players. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 6 D-NE10 SECTION 3 DISASSEMBLY Note : Disassemble the unit in the order as shown below. UPPER LID (SUB) ASSY MAIN BOARD, CD MECHANISM DECK (CDM-3325ER2) TURN TABLE MOTOR ASSY (M901), SLED MOTOR ASSY (M902), OPTICAL PICK-UP (DAX-25E) LIGHT GUIDE LENS CABINET (INNER) SET www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 7 D-NE10 6 5 7 upper lid (SUB) assy 1 two tapping screws 3 bracket (hinge L) 2 bracket (hinge R) 4 Close the cover until the tip of the cover of the top cover (SUB) assembly is left open by 5 mm, then slide the top cover (SUB) assembly in the direction of the arrow. Note : Follow the disassembly procedure in the numerical order given. 3-1. UPPER LID (SUB) ASSY www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 8 D-NE10 1 screw 2 light guide lens 3-2. LIGHT GUIDE LENS 3-3. CABINET (INNER) 1 eight screws 5 cabinet (inner) cabinet (lower) assy 3 lock claw (R) 2 lock claw (L) 4 spring (lock claw) 6 spring (upper lid) spring (lock claw) lock claw (L) lock claw (R) Note: It is recommended to visually check that the battery terminal board (+) is installed in the specified position after assembling the cabinet (INNER) because, in some cases, the battery terminal board (+) cannot be housed when assembling the cabinet (INNER). battery terminal board (+) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 9 D-NE10 3-4. MAIN BOARD, CD MECHANISM DECK (CDM-3325ER2) 2 connector (2P) 3 connector (4P) 4 flexible board (CN501) 6 CD mechanism deck (CDM-3325ER2) 5 three insulators qs MAIN board qd control button qf knob (hold) 1 spacer (disc) spacer (disc) 7 Remove two solders of the MAIN board. 8 battery terminal board (-) 0 battery terminal board (+) 9 Remove two solders of the MAIN board. qa static electricity incorrect operation prevention earth www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 10 D-NE10 1 three screws (B 1.7 × 4) 5 three screws (B 1.7 × 4) 3 sled motor assy (M902) 6 turn table motor assy (M901) 4 optical pick-up (DAX-25E) 2 gear cover chassis 3-5. TURN TABLE MOTOR ASSY (M901), SLED MOTOR ASSY (M902), OPTICAL PICK-UP (DAX-25E) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 11 D-NE10 The CD section adjustments are done automatically in this set. In case of operation check, confirm that RF level. Precautions for Check 1. Perform check in the order given. 2. Use YEDS-18 disc (Part No.: 3-702-101-01) unless otherwise indicated. 3. Power supply voltage requirement : DC3 V in terminals for the charging stand.(J401,402) VOLUME button : Minimum HOLD switch : OFF AVLS function setting : OFF G-PROTECTION function setting : 1 Checking Location: – MAIN board (Side A) – RF Level Check Condition: • Hold the set in horizontal state. Connection: Procedure: 1. Connect the oscilloscope to the test points TP649 (RF) and TP701 (AGND) on the MAIN board. 2. Set a disc. (YEDS-18) 3. Press the u button. 4. Check the oscilloscope waveform is as shown below. A good eye pattern means that the diamond shape (◊) in the center of the waveform can be clearly distinguished. RF Signal reference Waveform (Eye Pattern) VOLT/DIV : 100 mV (With the 10:1 probe in use) TIME/DIV : 500 ns To watch the eye pattern, set the oscilloscope to AC range and increase the vertical sensitivity of the oscilloscope for easy watch- ing. 5. Stop revolving of the disc motor by pressing the x button. Oscilloscope (AC range) + – MAIN board TP649 (RF) TP701 (AGND) 2 kΩ RF level 0.45 to 0.65 Vp-p 1 15 TP649 TP701(AGND) SECTION 4 ELECTRICAL CHECKING www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 12 D-NE10 Note: The components identified by mark 0 or dotted line with mark 0 are critical for safety. Replace only with part number specified. Note: Les composants identifiés par une marque 0 sont critiques pour la sécurité. Ne les remplacer que par une pièce portant le numéro spécifié. SECTION 5 DIAGRAMS Note on Printed Wiring Board • X : parts extracted from the component side. • Y : parts extracted from the conductor side. • : Pattern from the side which enables seeing. (The other layers' patterns are not indicated.) • MAIN board is multi-layer printed board. However, the pat- terns of intermediate-layer have not been included in the dia- gram. Caution: Pattern face side: Parts on the pattern face side seen from (Side B) the pattern face are indicated. Parts face side: Parts on the parts face side seen from (Side A) the parts face are indicated. NOTE FOR PRINTED WIRING BOARDS AND SCHEMATIC DIAGRAMS • WAVEFORMS Note on Schematic Diagram: • All capacitors are in µF unless otherwise noted. pF: µµF 50 WV or less are not indicated except for electrolytics and tantalums. • All resistors are in Ω and 1/4 W or less unless otherwise specified. • % : indicates tolerance. • C : panel designation. • A : B+ Line. • Total current is measured with CD installed. • Power voltage is dc 4.5 V and fed with regulated dc power supply from DC IN jack (J401). • Voltages and waveforms are dc with respect to ground in playback mode. no mark : CD PLAY * : Impossible to measure • Voltages are taken with a VOM (Input impedance 10 MΩ). Voltage variations may be noted due to normal production toler- ances. • Waveforms are taken with a oscilloscope. Voltage variations may be noted due to normal production toler- ances. • Circled numbers refer to waveforms. • Signal path. J : CD PLAY (ANALOG OUT) c : CD PLAY (OPTICAL OUT) ✩When IC802 is damaged, replace the MAIN board. 540 mVp-p 1 IC601 if RFAC 100mV/DIV, 400ns/DIV 2 IC601 rk XTAO 1V/DIV, 20ns/DIV 3 IC801 wk XIN 1V/DIV, 40ns/DIV 4 IC401 5 SYNC 1V/DIV, 2us/DIV 59ns 2.7 Vp-p 5 IC702 e; XTAL 1V/DIV, 20ns/DIV 44ns 2.8 Vp-p 5.7us 2.2 Vp-p 118ns 2.1 Vp-p www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 13 13 D-NE10 5-1. BLOCK DIAGRAM – MAIN SECTION -1 – • SIGNAL PATH : CD PLAY (ANALOG OUT) : CD PLAY (OPTICAL OUT) 1 2 7 IC601 RF AMP, DIGITAL SIGNAL PROCESSOR, DIGITAL SERVO PROCESSOR, D-RAM CONTROLLER DIGITAL OUT LPF SIGNAL PROCESSOR BLOCK MEMORY CONTROLLER, BASS BOOST BLOCK SERVO BLOCK MDS MDP SENS SCOR SDTO XTAI XTAO RFAC XSOE R4M XLAT CLOK DOUT XRAS XWE XCAS AOUT1 AOUTL, AOUTR AOUT2 FOK GFS RFDC B A SFDR SRDR FFDR FRDR TFDR TRDR D0-D3 A0-A10 WFCK XTAO XTAI E F 89 F 92 91 A B 88 84 RFDC RFAC E LASER DIODE OPTICAL PICK-UP BLOCK DAX-25E A A B RF E F B RF E F PD PD LD LD DETECTOR VCC X601 16.9344MHz A B 90 2, 3, 24, 25 9 – 12, 15 – 19, 21, 8 5 4 23 IC602 D-RAM D0 – D3 A0 – A10 XRAS DOUT XWE XCAS C D 100 99 SFDR SRDR 96 95 FFDR FRDR 98 97 52 53 48 49 50 51 38 36 46 44 42 40 TFDR TRDR M901 SLED MOTOR (FOCUS) (TRACKING) FI3 RI3 FI1 RI1 FI2 RI2 FO3 RO3 FO1 RO1 FO2 RO2 IC401 (1/3) FOCUS/TRACKING COIL DRIVER SLED MOTOR DRIVER M 24 22 32 65 23 20 21 52 85 88 87 83 84 86 MOTOR DRIVER 102 MDS 103 MDP 27 SCOR 104 27 21 24 25 26 30 32 34 10 23 C176 FOK R8M 12 HG_XSTB_O 13 HG_GUP_O XSOE SDTO SENS CLOK XLAT XSOE_O XIN FOKI MSDTO0_O SCOR_I MSDTI0_I MSCK_O XLAT0_O + IC403 (1/2) SWITCH XBRK 22 FG APWM + + U1 V1 W1 COM U V W IC401 (2/3) SPINDLE MOTOR DRIVER M902 SPINDLE MOTOR FG_I 58 MDP_SW 69 53 GFS GFS_I 28 4 XRST XRST_O IC801 (1/3) SYSTEM CONTROLLER MSDTO MSCK E G F SYNC 2-AXIS DEVICE 62 4, 3, 6, 5 116 – 113, 17 – 15, 13 – 11, 117 51 56 48 9 2 1 47 V U W CONTROLLER, H BRIDGE DRIVER 28 CONTROL CIRCUIT VCC3 OPGSW OPSTB MP3 DECODER IC702 EEPROM IC802 BCK 2 PCMD_O LRCK_O BCK_O PCMD 4 LRCK 1 XSK 2 XCS 1 DO 4 DI 3 PI3 13 PCMD_I LRCK_I BCK_I PF4 12 18 XRDE PI0 15 PI2 14 NRST 33 PF0 34 PF3 37 PC1 40 PC2 41 60 AT3_MP3_V_O 66 WAKEUP_K_O 11 REQ_I 20 SDIN_I 19 SDOUT_O PC0 38 18 SDCLK_O PC3 42 17 SDXLAT_O 67 EEP_CS_O X701 22MHz 29 XTAL EXTAL 30 108 106 110 109 107 111 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 14 14 D-NE10 • SIGNAL PATH : CD PLAY (ANALOG OUT) : CD PLAY (OPTICAL OUT) SYSTEM CONTROLLER IC801 (2/3) 77 HP_PWRSW 65 HP_LIN_SEL_O 6 BEEP_O JOGKEY_I/FAVKEY_I 36 XLED1_O 75 LID-SW_I 37 70 OPTPWRCTL_O 9 OPTOUT_I 8 LINEOUT_I 31 TSB OFF ON > HOLD S802 8 VCC1 VCC2 TSB RMKEY L-IN 5 R-IN 3 BEEP 16 MSW 2 MUTE 1 12 LOUT 14 ROUT HEADPHONE AMP IC301 (REMOTE) J301 VCPU LINE OUT (OPTICAL) VCC3 Q304, 804 SWITCH Q801(1/2) SWITCH Q801(2/2) LED DRIVER Q803 S811 x S812 (OPEN/CLOSE) D804 OPR XLED2_O 76 AD-KEY2 97 HOLD_I 40 FUNCTION KEY S803 - 809 AD-KEY1 96 AD-RMKEY 99 C D DOUT AOUTL, AOUTR AOUTL B+ SWITCH Q302, 303 MUTING CONTROL SWITCH Q301 AOUTR 7 AMUTE_O – MAIN SECTION -2 – w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 15 15 D-NE10 LINEAR CONSTANT CURRENT, CONSTANT VOLTAGE CHARGING BATTERY CHARGE CIRCUIT CHARGING BATTERY VOLTAGE DETECTOR CIRCUIT PRE-DRIVER SWITCHING POWER CIRCUIT Q402 CHARGE SWITCH Q401 B+ SWITCH Q406 EXTERNAL BATTERY DETECT SWITCHING POWER CIRCUIT INTERFACE VG POWER CIRCUIT CLK OR OSC 55 65 82 66 CHGSW RF1 VINDET RF41 RF41 RF4 RF4 VCC2 VCPU INP3 VCC2 VCPU VCC1 INM4 INM4 APCREF PAPC PA PC WAKE LATCH DATA CLOCK DATA CLOCK VLGO4 SYNC 8 7 78 100 99 97 6 10 61 9 96 70 86 60 90 72 5 MSDTO MSCK PD 32 LD E G F B A SYNC INP2 INP2 RS1 DCIN VIN INP3 VCC1 VCC4IN VCC3 VCC4 L2L RS1 58 RF1 CHGSW VIN 98 VINDET DCIN L2L 85 VDSW20 20 VCC3 VCC4IN LATCH WAKE VLGO2 BATM1 CHGMNT CHGMNT VLGO4 VLGO2 VG L5 3 2 VG L5 BATM1 RSTB XWAKE_O 8 XRESET_I 90 PWRLAT_O 93 AD-CHGMNT 57 VDSEL 95 AD-DCINMNT 94 AD-CHGSTMNT 92 AD-BATMNT IC801 (3/3) SYSTEM CONTROLLER VCC1 1.9V 59 VDRAM VCPU 1.9V VCC2 VIN VIN VIN VD VIN/VD IC601 IC602 91 VCC3 VCC4 76 VCC4 D404 D402 D401 L410 RECHARGEABLE BATTERY NH-14WM 1PC. 1.2V VIN J401 (EXT BATT) 38 EXTBAT_I IC401 (3/3) POWER CONTROL RV401 VCPU 92 SAW GEN. Q405 SWITCH Q404 SWITCH 74 77 J402 (CHARGING STAND) CHARGE D403 6 5 3 IC403 (2/2) SWITCH VDSW19 19 INP7 15 UPCKB7 13 Q403 SWITCH UPCK7 11 VLG07 14 IC701 IC702 AVD – POWER SECTION – w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 16 16 D-NE10 5-2. PRINTED WIRING BOARDS – MAIN BOARD (SIDE A) – E E 1 2 A B C D E F G 3 4 5 6 7 8 9 MAIN BOARD (SIDE A) OPTICAL PICK-UP BLOCK DAX-25E J301 1 2 1 4 1 15 M + - M901 SLED MOTOR M902 3 PHASE SPINDLE MOTOR (11) 11 OPR RECHARGEABLE BATTERY NH-14WM 1PCS.1.2V J402 (CHARGING STAND) J401 (EXT BATT) 1-860-218- LINE OUT (OPTICAL) (REMOTE) V U W • : Uses unleaded solder. • Semiconductor Location MAIN BOARD (SIDE A) Ref.No. Location D101 F-5 D202 F-5 D303 F-7 D804 B-1 Q304 F-6 Q804 E-6 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 17 17 D-NE10 5-3. PRINTED WIRING BOARDS – MAIN BOARD (SIDE B) – • : Uses unleaded solder. ✩When IC802 is damaged, replace the MAIN board. IC401 IC602 IC601 IC801 IC702 IC701 IC301 IC403 IC802 1 3 5 4 E E E E E E E u x > . ON OFF S812 (OPEN/CLOSE) 1 2 A B C D E F G 3 4 5 6 7 8 9 MAIN BOARD (SIDE B) (11) 11 PROGRAMMER > HOLD VOL 1-860-218- Ref.No. Location D302 F-4 D304 G-5 D305 F-4 D306 F-4 D308 G-5 D401 E-2 D402 E-2 D403 C-2 D404 D-2 D405 B-3 D406 C-4 D805 E-7 IC301 E-3 IC401 C-2 IC403 C-4 IC601 E-5 IC602 D-4 IC701 A-4 IC702 B-5 IC801 D-7 IC802 B-7 Q301 E-4 Q302 E-3 Q303 E-2 Q401 E-2 Q402 E-2 Q403 D-3 Q404 D-3 Q405 D-3 Q406 B-3 Q801 E-6 Q803 B-3 • Semiconductor Location MAIN BOARD (SIDE B) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 18 18 D-NE10 5-4. SCHEMATIC DIAGRAMS – MAIN BOARD (1/4) – 1.9 1.9 1 0 1.9 1.9 1.3 1.3 0.9 0.9 2.6 2.6 1.3 1.3 0 0 1.9 1.9 1.9 1 1 1 0.9 0.9 0.9 0.9 0.9 0.9 0.9 1.1 1.1 1.1 1.9 1.9 0.7 1.2 1.2 0.3 0.1 0.1 0.1 0 0 0 1.9 0.4 1 1.9 0 1.9 0 0 0 0 1.9 1 1 1 1 1 1.3 No mark : PLAY (servo on) 1.5 1 1 1 1 1.6 0.9 0.9 0.9 0.9 1 1 1.9 1.9 1.9 1.9 1.7 1.9 1.7 0 0.1 0.1 1.9 0 1.9 1 1.3 1.5 1 1 1 1 1 1.9 1 1 1 0.9 0.9 0.9 0.9 1.6 1 1 2 1 <1> <3> <4> 15P 4P 2P <5> <6> <7> <8> <9> <14> <15> <16> <20> <19> <18> <17> <21> <22> <23> <24> <25> <26> <27> <28> <30> <31> <32> <33> <34> <36> <29> <10> <11> <12> 0UH 0UH 0UH <13> MAIN BOARD (2/4) MAIN BOARD (3/4) MAIN BOARD (4/4) A B C IC601 MAIN BOARD (1/4) 1 2 1 2 3 4 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 V U W IC602 IC601 CXD3039AR IC602 MSM51X17400F-10TFSR1 X601 16.934MHz RF AMP DIGITAL SIGNAL PROCESSOR DIGITAL SERVO PROCESSOR D-RAM CONTROLLER D-RAM M901 SLED MOTOR M902 3 PHASE SPINDLE MOTOR OPTICAL PICK-UP BLOCK DAX-25E • See page 12 for Waveform. • See page 23 for IC Block Diagrams. w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 19 19 D-NE10 5-5. SCHEMATIC DIAGRAMS – MAIN BOARD (2/4) – No mark : PLAY (servo on) * : Impossible to measure 0.3 0 0 0 0.8 1.2 0.1 1.9 0.2 1.9 1.9 3.3 0.7 0.1 0.2 0 0.7 0.7 0 0.7 0 0.1 0.3 0.1 0.2 1.2 0.1 0.1 1.2 0 0 1.3 0 0.4 1.2 0.4 1.2 0.4 0.3 1.2 0.4 1.9 5.9 1.3 0.6 0.6 0.4 0.1 7 0 1.9 1 0.4 0.4 0.4 1.2 1.2 7 0.9 0 1.9 1.9 1.9 1.9 0.3 1.5 1.9 1.9 1.1 1.2 1.2 1.2 1.9 1.2 1.2 2.7 2.4 0.6 0.6 0.2 0.1 0.2 0.2 0.9 0.5 0.2 * 1.2 1.9 0.7 0.7 0 2.7 1.2 7 1.3 0 1.2 1.2 1.3 5.9 1.2 1.2 0 0.3 1.9 0 0 1.4 1.9 1.9 0 0 0 0.1 0.7 0.1 4 <37> <38> <39> <40> <41> <42> <43> <1> <3> <4> <5> <6> <7> <8> <9> <10> <11> <12> <13> <14> <15> <16> <20> <19> <18> <17> A D IC401 IC403 1P 1P 2SD2652T106 2SA1602TP-1EF MAIN BOARD (4/4) MAIN BOARD (1/4) MAIN BOARD (2/4) IC401 TB2166FG IC403 SN74LVC2G66DCUR • TOTAL CURRENT PLAY : 110mA STOP : 53mA FF : 100mA FR : 150mA RECHARGEABLE BATTERY NH-14WM 1PCS.1.2V SPINDLE MOTOR DRIVER CHARGE SWITCH B+ SWITCH EXTERNAL BATTERY DETECT SWITCH SWITCH SWITCH SWITCH J401 (EXT BATT) J402 (CHARGING STAND) • See page 12 for Waveform. w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 20 20 D-NE10 5-6. SCHEMATIC DIAGRAMS – MAIN BOARD (3/4) – 1.9 1.9 1.9 1.9 1.9 1.9 1.9 1.9 1.9 1.5 1.9 1.5 0 0 0 2.7 2.7 0 0 2.7 1.9 0 1.9 1.5 1.5 1.9 1.9 1.9 1.5 1.9 2.7 2.7 1.4 1.4 0 0 0 0 0 0 0 1.3 0.6 1.3 0.6 1.2 0.6 1.3 2.4 2.4 0 2.7 0 1.9 2.7 2.1 0.3 1.3 1.2 1.3 2.7 2.7 0 1.6 5 No mark : PLAY (servo on) <44> <45> <46> <48> <47> <49> <50> <51> <52> <53> <55> <54> <56> <57> <59> <21> <22> <23> <24> <25> <26> <27> <28> <30> <31> <32> <33> <34> <29> <58> B E IC702 IC301 IC701 MAIN BOARD (1/4) MAIN BOARD (4/4) 10V 10V 10V MAIN BOARD (3/4) Q303 BCR119W-GEG-E6327 Q303 BCR119W-GEG-E6327 IC702 CXR710160-207R MP3 DECODER SWITCH IC701 XN0NE9200LS0 B+ SWITCH B+ SWITCH IC301 AN17020B-E1 SWITCH MUTING CONTROL SWITCH S812 (OPEN/CLOSE) > HOLD S802 OFF ON (REMOTE) J301 LINE OUT (OPTICAL) • See page 12 for Waveform. • See page 23 for IC Block Diagrams. w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 21 21 D-NE10 5-7. SCHEMATIC DIAGRAMS – MAIN BOARD (4/4) – 1.9 0 1.9 1.9 1.9 0 1.9 0 1.2 1.9 1.9 1.8 1.9 0 1.6 1.9 1.9 0 0 0 1.9 0 1.9 1.9 0.2 1.3 0.2 1.9 1.9 1.9 1.9 0 1.9 0 1 0 0 0 0 0 1.9 1.9 1.9 1.9 0 1.9 1.9 1.9 0 1.9 1.9 1.9 0 1.9 1.9 1.9 1.9 0 1.9 0 1.7 0 0 1 1.9 1.9 1 3 1.9 1.9 1.9 1.9 1.9 0.4 0.1 0 * 0 * 0 2.4 0 1.9 No mark : PLAY (servo on) * : Impossible to measure MAIN BOARD (1/4) MAIN BOARD (3/4) MAIN BOARD (2/4) <44> <45> <46> <48> <47> <49> <50> <51> <52> <53> <55> <54> <56> <57> <36> <59> <58> <37> <38> <39> <40> <41> <42> <43> C D E IC801 IC802 10P u > . + – x + – MAIN BOARD (4/4) VOL TP806 TMP91CY28FG-2772-01 IC801 SYSTEM CONTROLLER SWITCH SWITCH SWITCH EEPROM PROGRAMMER • See page 12 for Waveform. ✩When IC802 is damaged, replace the MAIN board. w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 22 22 D-NE10 • IC Block Diagrams IC301 AN17020B-E1 IC702 CXR170160-207R + - + - RF2 14 13 16 15 12 11 10 9 3 4 5 6 7 8 2 1 BEEP MUTE RF1 HP/Line SW BEEP GA-R ROUT GND LOUT GA-L VCC2 VCC2 MUTE MSW R-IN GND L-IN HVCC1 VREF VCC1 ARM77TDMI CPU CORE VIRTUAL ENGINE CORE HUFFMAN HW MAGIC GATE CORE CLOCK GENERATOR/ SYSTEM CONTROLLER DMAC (CH0) DMAC (CH1) DMAC (CH2) WATCHDOG TIMER PRESCALLER/ TIME BASETIMER RAM 160K BYTES RAM 512K BYTES EEPROM SERIAL INTERFACE CD-ROM INTERFACE DAC INTERFACE DMAC (CH3) SERIAL INTERFACE (CH0) UART (CH0) UART (CH1) RAM 2 8 2 NTRST TDO TMS VDIO3 TDI TCK TEST0 DVSS1 DVDD3 TEST2 TEST1 TRST(TEST4) TEST3 XOUT(TEST5) TACK(TEST6) VDIO2 LRCK BCK VDIOCD0 PCMD DVDD4 TAPTDO SCANEN DCDD0 DVSS0 DVIO0 VDIOCD1 PF4/XRDE P13/BCKO P12/LRCKO P10/PCMDO EVA DVSS2 DVDD2 PC3/SCS0 PC2/SI0 PC1/SO0 VDIOCD2 PC0/SCK0 PF3/T3 PF2/EC2/INT4 PF1/T1 PF0/EC0/INT3 NRST KCS VDIO1 KDO KDI KRB DVDD1 DVSS3 AVDPLL AVSPLL AVSSOSC AVDMO EXTAL XTAL XIN OSCSEL KCLK INTERRUPT CONTROLLER 8BIT TIMER (CH7) 8BIT TIMER (CH6) 8BIT TIMER (CH5) 8BIT TIMER (CH4) 8BIT TIME 8BIT TIMER/COUNTER (CH2) 8BIT TIMER (CH1) 8BIT TIMER/COUNTER (CH0) 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 42 41 40 39 38 37 36 35 34 33 44 43 PE3/RxD1 48 PE2/TxD1 47 PE1/RxD0 46 PE0/TxD0 45 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 64 63 62 61 60 59 58 57 56 55 53 54 52 51 50 49 w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 23 D-NE10 5-8. IC PIN FUNCTION DESCRIPTIONS Pin No. Pin Name I/O Description 1 XRAS O Row address strobe signal output to the D-RAM 2 XWE O Data input enable signal output to the D-RAM 3 to 6 D1, D0, D3, D2 I/O Two-way data bus with the D-RAM 7 DCLK O Not used 8 DCKE O Not used 9 XCAS O Column address strobe signal output to the D-RAM 10 WFCK O WFCK signal output terminal Not used 11 to 13 A9 to A7 O Address signal output to the D-RAM 14 DVSS — Ground terminal (for D-RAM interface) 15 to 17 A6 to A4 O Address signal output to the D-RAM 18 XRDE I D-RAM read enable signal input terminal 19 VDD0 — Power supply terminal (digital system) 20 CLOCK I Serial data transfer clock input from the system controller 21 SDTO I Serial data input from the system controller 22 SENS O Serial data output to the system controller 23 XLAT I Serial data latch pulse signal input from the system controller 24 XSOE I Serial data output enable signal input from the system controller 25 SYSM I Analog muting on/off control signal input “H”: muting on Not used 26 WDCK O GRSCOR signal output to the system controller Not used 27 SCOR O Subcode sync (S0+S1) detection signal output to the system controller 28 XRST I Reset signal input from the system controller “L”: reset 29 PWMI I Spindle motor external control signal input terminal Not used 30 XQOK I Subcode Q OK signal input terminal Not used 31 XWRE I D-RAM write enable signal input terminal Not used 32 R8M O System clock output to the system controller 33 VSS0 — Ground terminal (digital system) 34 SQCK I SQSO readout clock input terminal Not used 35 SCLK I SENS serial data read clock input terminal Not used 36 SQSO O CD text data output terminal Not used 37 XEMP O D-RAM read prohibition signal output terminal Not used 38 XWIH O D-RAM write prohibition signal output terminal Not used 39 SBSO O Subcode P to W serial data output terminal Not used 40 EXCK O SQSO readout clock output terminal Not used 41 XTSL I Input terminal for the system clock frequency setting “L”: 16.9344 MHz, “H”: 33.8688MHz (fixed at “L” in this set) 42 HVSS — Ground terminal (for headphone) 43 HPL O PDM signal output for L-ch headphone to the headphone amplifier Not used 44 HPR O PDM signal output for R-ch headphone to the headphone amplifier Not used 45 HPVDD — Power supply terminal (for headphone) 46 XVDD — Power supply terminal (for master clock) 47 XTAI I System clock input terminal (16.9344 MHz) 48 XTAO O System clock output terminal (16.9344 MHz) 49 XVSS — Ground terminal (for master clock) 50 AVDD1 — Power supply terminal (analog system) 51 AOUT1 O L-ch analog audio signal output 52 VREFL O L-ch reference voltage output terminal • IC601 CXD3039AR (RF AMP, DIGITAL SIGNAL PROCESSOR, DIGITAL SERVO PROCESSOR, D-RAM CONTROLLER) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 24 D-NE10 Pin No. Pin Name I/O Description 53, 54 AVSS1, AVSS2 — Ground terminal (analog system) 55 VREFR O R-ch reference voltage output terminal 56 AOUT2 O R-ch analog audio signal output 57 AVDD2 — Power supply terminal (analog system) 58 TES1 I Input terminal for the test (normally: fixed at “L”) 59 TEST I Input terminal for the test (normally: fixed at “L”) 60 VSS1 — Ground terminal (digital system) 61 LRMU O Muting on/off control signal output to the audio line and the headphone amplifier “H”: muting on Not used 62 DOUT O Digital audio signal output 63 ATSK I/O Input/output terminal for anti-shock Not used 64 DFCT I/O Defect signal input/output terminal Not used 65 FOK O Focus OK signal output to the system controller “L”: NG, “H”: OK 66 MIRR I/O Defect signal input/output terminal Not used 67 COUT I/O Numbers of track counted signal input/output terminal Not used 68 C2PO O C2PO signal output terminal Not used 69 GFS O GFS signal output terminal 70 XUGF O XUGF signal output terminal Not used 71 XPCK O XPCK signal output terminal Not used 72 VDD1 — Power supply terminal (digital system) 73 PCO O Charge pump output for master PLL 74 FILI I Filter input for master PLL 75 FILO O Filter output for master PLL 76 CLTV I VCO1 control voltage input terminal for multiplier 77 VCTL I VCO2 control voltage input terminal for broad-band EFM PLL 78 VPCO O Charge pump output terminal for broad-band EFM PLL 79 AVSS3 — Ground terminal (analog system) 80 ASYO O EFM full-swing output terminal 81 ASYI I Asymmetry comparator voltage input terminal 82 BIAS I Asymmetry circuit constant current input terminal 83 AVDD3 — Power supply terminal (analog system) 84 RFAC I EFM signal input from the optical pick-up 85 AVDD0 — Power supply terminal (analog system) 86 IGEN I Stabilized current input for operational amplifiers 87 AVSS0 — Ground terminal (analog system) 88 RFDC I RF signal input from the optical pick-up 89 E I E signal input from the optical pick-up 90 F I F signal input from the optical pick-up 91 B I B signal input from the optical pick-up 92 A I A signal input from the optical pick-up 93 VC I Middle point voltage input terminal Not used 94 VSS3 — Ground terminal (digital system) 95 FRDR O Focus servo drive signal (–) output to the IC401 96 FFDR O Focus servo drive signal (+) output to the IC401 97 TRDR O Tracking servo drive signal (–) output to the IC401 98 TFDR O Tracking servo drive signal (+) output to the IC401 99 SRDR O Sled servo drive signal (–) output to the IC401 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 25 D-NE10 Pin No. Pin Name I/O Description 100 SFDR O Sled servo drive signal (+) output to the IC401 101 SSTP I Disc inner position detection signal input terminal Not used 102 MDS O Spindle motor drive signal output to the spindle motor driver 103 MDP O Spindle motor servo control signal output to the spindle motor driver 104 C176 O 176.4 kHz clock output to the power control and spindle motor driver 105 VDD2 — Power supply terminal (digital system) 106 LRCK O L/R sampling clock (44.1 kHz) output terminal 107 LRCKI I L/R sampling clock (44.1 kHz) input terminal 108 PCMD O Serial data output terminal 109 PCMDI I Serial data input terminal 110 BCKO O Bit clock (2.8224 MHz) output terminal 111 BCKI I Bit clock (2.8224 MHz) input terminal 112 DVDD — Power supply terminal (for D-RAM interface) 113 to 117 A3 to A0, A10 O Address signal output to the D-RAM 118 to 120 A11 to A13 O Address signal output terminal to the D-RAM Not used www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 26 D-NE10 • IC801 TMP91CY28FG-2772-01 (SYSTEM CONTROLLER) Pin No. 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 to 51 52 53 54 55 56 57 I/O — — — O O O O I I I I O O I I O O O O I O I O I — O — I I I I/O O O O I I I I I I I I — I/O I I O O O O Pin Name GND GND VCPU XRST_O PWM_O BEEP_O AMUTE_O LINEOUT_I OPTOUT_I FG_I REQ_I HG-XSTB_O HG-GUP_O RE1_I RE2_I LCD_REQ_O SDXLAT_O SDCLK_O SDOUT_O SDIN_I DTS_SDTO DTS_SDTI DTS_SCK AM0_I VCPU XOUT GND XIN AM1_I XRESET_I TSB XWAKE_O EMU0_O EMU1_O ACKCD_I JOGKEY_I/FAVKEY_I LID-SW_I EXTBAT_I HP_TYPE_I HOLD_I X_PEQ_EN_I TEST_I NC AD0 to AD7 FOK_I GFS_I TUPWRON_O CDON_O AUD_SEL_O VDSEL Description Reference voltage terminal (A/D converter) Ground terminal (A/D converter) Power supply terminal (A/D converter) Reset signal output to the DSP (IC601) Not used (open) BEEP signal output Muting signal output to the headphone amplifier (IC301) Line plug in detection signal input (“H” : line plug in) Optical plug in detection signal input (“H” : optical plug in) FG (3 phase drive) signal input from the power control (IC401) Request signal input from the MP3 decoder (IC702) HG sleep mode signal output to the optical-pickup HG gain up signal output to the optical-pickup Not used (open) Not used (open) Not used (open) Serial data latch signal output to the MP3 decoder (IC702) Clock output to the MP3 decoder (IC702) Serial data output to the MP3 decoder (IC702) Serial data input from the MP3 decoder (IC702) Not used Not used Not used Not used (fixed at “H”) Power supply terminal Clock output (not used) Ground terminal Clock input Not used (fixed at “H”) Reset signal input (“L” : reset) Data input/output from/to the remote control Wake signal output to the power control (IC401) (“L” : running) Not used (open) Not used (open) Not used (fixed at “L”) Key signal input from the jog key or the remote control key Lid open/close detection signal input (“H” : lid open) External battery in detection signal input (“H” : external battery in) Not used HOLD switch detection signal input (“H” : HOLD on) Not used Test mode setting terminal (“L” : test mode) Not used (open) Not used (open) FOK signal input from the DSP (IC601) GFS signal input from the DSP (IC601) Not used (open) Not used (open) Not used (open) Power supply voltage selection signal output www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 27 D-NE10 Pin No. 58 59 60 61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80 81 82 83 84 85 86 87 88 89 90 91 92 93 94 95 96 97 98 99 100 I/O O O O O — I — O O O I O O O O O O O O O I I I I I O O I I O O — O — I I I I I I I I — Pin Name MDP_SW DTS_RST_O AT3_MP3_V_O P/S_O GND XNMI_I VCPU HP_LIN_SEL_O WAKEUP_K_O EEP_CS_O TUON_I LCD_A0 OPTPWRCTL_O XRD_O XWR_O LCD-XRST_O XLCD-BL_O XLED1_O XLED2_O HP_PWRSW BOOT XBAT_1CELL_I DMUTE_I XCEX_I DISPLAY_TYPE_I MSCK0_O MSDTO0_O MSDTI0_I SCOR_I XLAT0_O XSOE_O VCPU PWRLAT_O GND AD-BATMNT AD-CHGMNT AD-CHGSTMNT AD-DCINMNT AD-KEY1 AD-KEY2 AD-KEY3 AD-RMKEY VCPU Description Spindle motor control switch signal output Not used (open) Reset signal output to the MP3 decoder (IC702) Not used (open) Ground terminal Not used (fixed at “H”) Power supply terminal Headphone or line out selection control signal output Wakeup signal output to the MP3 decoder (IC702) Chip select signal output to the EEPROM (IC802) Not used (fixed at “H”) Not used (open) Optical output power supply control signal output Not used (open) Not used (open) Not used (open) Not used (open) LED control signal output LED control signal output Headphone amplifier power supply on/off signal output BOOT signal input Not used (fixed at “L”) Muting signal input from the DSP (IC601) Not used Not used (open) Not used (fixed at “L”) Clock signal output to the DSP (IC601) and the power control (IC401) Serial data output to the DSP (IC601) and the power control (IC401) SENS signal input from the DSP (IC601) SCOR signal input from the DSP (IC601) Latch signal output to the DSP (IC601) Serial data output enable signal output to the DSP (IC601) Power supply terminal Data latch signal output to the power control (IC401) Ground terminal Batttery monitoring signal input Charge monitoring signal input Charge stand monitoring signal input DC in monitoring signal input Key 1 signal A/D input Key 2 signal A/D input Key 3 signal A/D input Not used Remote control key signal A/D input Reference voltage terminal (A/D converter) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com SECTION 6 EXPLODED VIEWS 28 D-NE10 The components identified by mark 0 or dotted line with mark 0 are critical for safety. Replace only with part number specified. Les composants identifiés par une marque 0 sont critiques pour la sécurité. Ne les remplacer que par une pièce portant le numéro spécifié. NOTE: • -XX, -X mean standardized parts, so they may have some differences from the original one. • Items marked “*” are not stocked since they are seldom required for routine service. Some delay should be anticipated when ordering these items. • The mechanical parts with no reference number in the exploded views are not supplied. • Color Indication of Appearance Parts Example: KNOB, BALANCE (WHITE) . . . (RED) ↑ ↑ Parts of Color Cabinet’s Color • Accessories are given in the last of electrical parts list. • Abbreviation AUS : Australian model CND: Canadian model CH : Chinese model E18 : 100-230 V AC area in E model EA : Saudi Arabia model EE : East European model HK : Hong Kong model JE : Tourist model KR : Korean model TW : Taiwan model Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks 6-1. UPPER LID (SUB) ASSY 1 X-3384-910-1 LID ASSY, UPPER (SVX)(FOR SILVER) 1 X-3384-908-1 LID ASSY, UPPER (SVX)(FOR BLACK) (EXCEPT CND,TW) 1 X-3384-909-1 LID ASSY, UPPER (SVX)(FOR GOLD) (EXCEPT CND,TW) 2 3-252-725-01 SPACER CDM 3 3-258-913-02 LENS (LED) 4 3-234-449-19 SCREW (M1.4) 5 3-254-022-11 SCREW 6 3-258-898-01 BRACKET (HINGE L) 7 3-258-897-01 BRACKET (HINGE R) 1 7 3 6 5 5 2 4 cabinet (lower) assy Ver 1.2 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 29 D-NE10 Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks 6-2. CABINET (LOWER) ASSY 59 58 54 53 52 62 63 51 60 61 57 56 55 CD mechanism deck section (CDM-3325ER2) not supplied 64 not supplied 51 3-258-906-01 KNOB (HOLD) 52 3-258-907-01 BUTTON, CONTROL 53 3-258-908-01 TERMINAL BOARD (+), BATTERY 54 3-258-909-01 TERMINAL BOARD (-), BATTERY 55 3-258-915-01 CLAW (R), LOCK 56 3-258-914-01 CLAW (L), LOCK 57 3-258-894-01 SPRING (LOCK CLAW) 58 3-258-918-11 LID, BATTERY CASE 59 3-245-709-01 SCREW 60 3-258-896-01 CABINET (INNER) 61 3-245-331-02 INSULATOR 62 3-258-899-01 SPRING (UPPER LID) * 63 X-3384-670-1 MAIN BOARD ASSY (SERVICE) (EXCEPT AEP,UK,EE) * 63 X-3384-789-1 MAIN BOARD ASSY (SERVICE)(AEP,UK,EE) 64 X-3384-812-2 CABINET (LOWER) ASSY (S)(SILVER) (EA,KR,CH,AUS,JE) 64 X-3384-816-2 CABINET (LOWER) ASSY (B)(BLACK) (EA,KR,CH,AUS,JE) 64 X-3384-817-2 CABINET (LOWER) ASSY (G)(GOLD) (EA,KR,CH,AUS,JE) 64 X-3384-818-2 CABINET (LOWER) ASSY (S)(SILVER) (AEP,UK,E) 64 X-3384-819-2 CABINET (LOWER) ASSY (S)(SILVER)(E18,HK) 64 X-3384-820-2 CABINET (LOWER) ASSY (B)(BLACK)(E18,HK) 64 X-3384-822-2 CABINET (LOWER) ASSY (S)(SILVER) (US,CND,TW) Ver 1.2 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 30 D-NE10 Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks 6-3. CD MECHANISM DECK SECTION (CDM-3325ER2) 101 108 103 106 105 107 111 109 110 101 104 102 M901 M902 The components identified by mark 0 or dotted line with mark 0 are critical for safety. Replace only with part number specified. Les composants identifiés par une marque 0 sont critiques pour la sécurité. Ne les remplacer que par une pièce portant le numéro spécifié. 101 3-318-203-61 SCREW (B1.7X4), TAPPING 0102 X-3380-950-1 OPTICAL PICK-UP (DAX-25E) 103 3-221-473-01 COVER, GEAR 104 3-221-472-02 CHASSIS 105 3-221-474-01 SPRING, SLED 106 A-3331-663-A SCREW (FEED) ASSY 107 3-221-268-01 GEAR (B) 108 3-221-475-01 SHAFT, STANDARD 109 3-222-298-01 RACK 110 3-222-299-01 SPRING, RACK RETAINER 111 3-348-998-31 SCREW (M1.4X2.5), TAPPING, PAN M901 A-3608-777-A MOTOR ASSY, TURN TABLE M902 A-3174-850-A MOTOR ASSY, SLED www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 31 D-NE10 NOTE: • Due to standardization, replacements in the parts list may be different from the parts specified in the diagrams or the components used on the set. • -XX, -X mean standardized parts, so they may have some difference from the original one. • Items marked “*” are not stocked since they are seldom required for routine service. Some delay should be anticipated when ordering these items. • CAPACITORS: uF: µF • RESISTORS All resistors are in ohms. METAL: metal-film resistor METAL OXIDE: Metal Oxide-film resistor F: nonflammable • COILS uH: µH • Abbreviation AUS : Australian model CND: Canadian model CH : Chinese model E18 : 100-230 V AC area in E model EE : East European model HK : Hong Kong model JE : Tourist model KR : Korean model TW : Taiwan model When indicating parts by reference number, please include the board name. Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks SECTION 7 ELECTRICAL PARTS LIST • SEMICONDUCTORS In each case, u: µ, for example: uA...: µA... , uPA... , µPA... , uPB... , µPB... , uPC... , µPC... , uPD..., µPD... The components identified by mark 0 or dotted line with mark 0 are critical for safety. Replace only with part number specified. Les composants identifiés par une marque 0 sont critiques pour la sécurité. Ne les remplacer que par une pièce portant le numéro spécifié. MAIN * X-3384-670-1 MAIN BOARD ASSY (SERVICE) (EXCEPT AEP,UK,EE) * X-3384-789-1 MAIN BOARD ASSY (SERVICE)(AEP,UK,EE) ************************* 3-258-908-01 TERMINAL BOARD (+), BATTERY 3-258-909-01 TERMINAL BOARD (-), BATTERY < CAPACITOR > C104 1-109-982-11 CERAMIC CHIP 1uF 10.00% 10V C105 1-164-935-11 CERAMIC CHIP 470PF 10.00% 50V C106 1-137-859-11 TANTAL. CHIP 220uF 20% 4V C107 1-135-149-21 TANTALUM CHIP 2.2uF 20% 10V C108 1-164-943-11 CERAMIC CHIP 0.01uF 10.00% 16V C204 1-109-982-11 CERAMIC CHIP 1uF 10.00% 10V C205 1-164-935-11 CERAMIC CHIP 470PF 10.00% 50V C206 1-137-859-11 TANTAL. CHIP 220uF 20% 4V C207 1-135-149-21 TANTALUM CHIP 2.2uF 20% 10V C208 1-164-943-11 CERAMIC CHIP 0.01uF 10.00% 16V C301 1-100-539-91 TANTAL. CHIP 47uF 20% 6.3V C302 1-137-900-21 TANTAL. CHIP 22uF 20% 4V C303 1-164-943-11 CERAMIC CHIP 0.01uF 10.00% 16V C304 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V C305 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V C306 1-135-210-11 TANTALUM CHIP 4.7uF 20% 10V C307 1-137-859-11 TANTAL. CHIP 220uF 20% 4V C308 1-137-900-21 TANTAL. CHIP 22uF 20% 4V C309 1-100-419-21 TANTAL. CHIP 100uF 20% 6.3V C311 1-164-941-11 CERAMIC CHIP 0.0047uF 10.00% 16V C312 1-125-777-11 CERAMIC CHIP 0.1uF 10.00% 10V C313 1-117-720-11 CERAMIC CHIP 4.7uF 10V C401 1-115-156-11 CERAMIC CHIP 1uF 10V C402 1-107-820-11 CERAMIC CHIP 0.1uF 16V C404 1-128-829-91 TANTAL. CHIP 220uF 20% 6.3V C405 1-127-715-91 CERAMIC CHIP 0.22uF 10% 16V C406 1-131-862-91 TANTAL. CHIP 47uF 20% 4V C407 1-137-859-11 TANTAL. CHIP 220uF 20% 4V C408 1-164-937-11 CERAMIC CHIP 0.001uF 10.00% 50V C409 1-125-777-11 CERAMIC CHIP 0.1uF 10.00% 10V C410 1-107-819-11 CERAMIC CHIP 0.022uF 10.00% 16V C411 1-164-935-11 CERAMIC CHIP 470PF 10.00% 50V C412 1-164-943-11 CERAMIC CHIP 0.01uF 10.00% 16V C413 1-164-939-11 CERAMIC CHIP 0.0022uF 10.00% 50V C414 1-107-820-11 CERAMIC CHIP 0.1uF 16V C415 1-107-820-11 CERAMIC CHIP 0.1uF 16V C416 1-131-862-91 TANTAL. CHIP 47uF 20% 4V C417 1-107-820-11 CERAMIC CHIP 0.1uF 16V C418 1-137-739-91 TANTAL. CHIP 22uF 20% 6.3V C419 1-107-820-11 CERAMIC CHIP 0.1uF 16V C420 1-131-862-91 TANTAL. CHIP 47uF 20% 4V C421 1-100-419-21 TANTAL. CHIP 100uF 20% 6.3V C422 1-107-820-11 CERAMIC CHIP 0.1uF 16V C423 1-100-539-91 TANTAL. CHIP 47uF 20% 6.3V C424 1-127-688-21 TANTAL. CHIP 10uF 20% 6.3V C425 1-164-943-11 CERAMIC CHIP 0.01uF 10.00% 16V C426 1-164-943-11 CERAMIC CHIP 0.01uF 10.00% 16V C427 1-119-923-11 CERAMIC CHIP 0.047uF 10.00% 10V C428 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V C429 1-125-777-11 CERAMIC CHIP 0.1uF 10.00% 10V C430 1-125-777-11 CERAMIC CHIP 0.1uF 10.00% 10V C431 1-107-820-11 CERAMIC CHIP 0.1uF 16V C432 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V C433 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V C434 1-164-937-11 CERAMIC CHIP 0.001uF 10.00% 50V C435 1-164-937-11 CERAMIC CHIP 0.001uF 10.00% 50V C436 1-164-937-11 CERAMIC CHIP 0.001uF 10.00% 50V C438 1-164-943-11 CERAMIC CHIP 0.01uF 10.00% 16V C439 1-137-910-11 TANTAL. CHIP 10uF 20% 16V C440 1-117-720-11 CERAMIC CHIP 4.7uF 10V C442 1-164-935-11 CERAMIC CHIP 470PF 10.00% 50V C443 1-164-943-11 CERAMIC CHIP 0.01uF 10.00% 16V C444 1-164-866-11 CERAMIC CHIP 47PF 5.00% 50V C445 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V C446 1-125-891-11 CERAMIC CHIP 0.47uF 10.00% 10V C447 1-104-851-11 TANTAL. CHIP 10uF 20.00% 10V C448 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V C449 1-100-419-21 TANTAL. CHIP 100uF 20% 6.3V C450 1-137-740-91 TANTAL. CHIP 47uF 20% 6.3V C451 1-125-777-11 CERAMIC CHIP 0.1uF 10.00% 10V C452 1-107-820-11 CERAMIC CHIP 0.1uF 16V C453 1-119-751-11 TANTAL. CHIP 22uF 20.00% 16V C455 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V C456 1-127-715-91 CERAMIC CHIP 0.22uF 10% 16V C601 1-119-750-11 TANTAL. CHIP 22uF 20.00% 6.3V C602 1-107-820-11 CERAMIC CHIP 0.1uF 16V C603 1-125-777-11 CERAMIC CHIP 0.1uF 10.00% 10V C604 1-164-939-11 CERAMIC CHIP 0.0022uF 10.00% 50V www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks 32 D-NE10 MAIN C605 1-164-858-11 CERAMIC CHIP 22PF 5.00% 50V C606 1-131-862-91 TANTAL. CHIP 47uF 20% 4V C607 1-107-820-11 CERAMIC CHIP 0.1uF 16V C608 1-164-941-11 CERAMIC CHIP 0.0047uF 10.00% 16V C609 1-117-863-11 CERAMIC CHIP 0.47uF 10.00% 6.3V C610 1-117-863-11 CERAMIC CHIP 0.47uF 10.00% 6.3V C611 1-164-874-11 CERAMIC CHIP 100PF 5.00% 50V C612 1-115-156-11 CERAMIC CHIP 1uF 10V C613 1-164-935-11 CERAMIC CHIP 470PF 10.00% 50V C614 1-164-935-11 CERAMIC CHIP 470PF 10.00% 50V C615 1-164-935-11 CERAMIC CHIP 470PF 10.00% 50V C616 1-164-935-11 CERAMIC CHIP 470PF 10.00% 50V C617 1-119-750-11 TANTAL. CHIP 22uF 20.00% 6.3V C619 1-100-539-91 TANTAL. CHIP 47uF 20% 6.3V C620 1-164-850-11 CERAMIC CHIP 10PF 0.50PF 50V C621 1-125-777-11 CERAMIC CHIP 0.1uF 10.00% 10V C622 1-164-858-11 CERAMIC CHIP 22PF 5.00% 50V C623 1-115-156-11 CERAMIC CHIP 1uF 10V C625 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V C627 1-107-820-11 CERAMIC CHIP 0.1uF 16V C628 1-164-937-11 CERAMIC CHIP 0.001uF 10.00% 50V C629 1-127-688-21 TANTAL. CHIP 10uF 20% 6.3V C632 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V C702 1-107-820-11 CERAMIC CHIP 0.1uF 16V C703 1-107-820-11 CERAMIC CHIP 0.1uF 16V C704 1-125-777-11 CERAMIC CHIP 0.1uF 10.00% 10V C706 1-104-847-11 TANTAL. CHIP 22uF 20.00% 4V C708 1-107-820-11 CERAMIC CHIP 0.1uF 16V C709 1-107-820-11 CERAMIC CHIP 0.1uF 16V C710 1-107-820-11 CERAMIC CHIP 0.1uF 16V C711 1-107-820-11 CERAMIC CHIP 0.1uF 16V C712 1-107-820-11 CERAMIC CHIP 0.1uF 16V C713 1-107-820-11 CERAMIC CHIP 0.1uF 16V C714 1-107-820-11 CERAMIC CHIP 0.1uF 16V C715 1-119-750-11 TANTAL. CHIP 22uF 20.00% 6.3V C716 1-107-820-11 CERAMIC CHIP 0.1uF 16V C717 1-131-862-91 TANTAL. CHIP 47uF 20% 4V C718 1-107-820-11 CERAMIC CHIP 0.1uF 16V C719 1-107-820-11 CERAMIC CHIP 0.1uF 16V C720 1-107-820-11 CERAMIC CHIP 0.1uF 16V C801 1-164-941-11 CERAMIC CHIP 0.0047uF 10.00% 16V C802 1-164-941-11 CERAMIC CHIP 0.0047uF 10.00% 16V C803 1-164-941-11 CERAMIC CHIP 0.0047uF 10.00% 16V C804 1-164-941-11 CERAMIC CHIP 0.0047uF 10.00% 16V C805 1-164-941-11 CERAMIC CHIP 0.0047uF 10.00% 16V C806 1-164-941-11 CERAMIC CHIP 0.0047uF 10.00% 16V C807 1-164-937-11 CERAMIC CHIP 0.001uF 10.00% 50V C808 1-107-820-11 CERAMIC CHIP 0.1uF 16V C809 1-107-820-11 CERAMIC CHIP 0.1uF 16V C810 1-107-820-11 CERAMIC CHIP 0.1uF 16V C811 1-107-820-11 CERAMIC CHIP 0.1uF 16V C812 1-107-820-11 CERAMIC CHIP 0.1uF 16V C814 1-115-156-11 CERAMIC CHIP 1uF 10V C815 1-164-941-11 CERAMIC CHIP 0.0047uF 10.00% 16V < CONNECTOR > * CN602 1-785-877-21 HOUSING, CONNECTOR 4P CN603 1-784-342-21 HOUSING, CONNECTOR 2P CN604 1-818-127-11 CONNECTOR, FFC/FPC 15P (ZIF L) < DIODE > D101 8-719-422-37 DIODE MA8051-TX D202 8-719-422-37 DIODE MA8051-TX D302 8-719-046-91 DIODE MA2S111-TX D303 8-719-422-37 DIODE MA8051-TX D304 8-719-422-37 DIODE MA8051-TX D305 8-719-422-37 DIODE MA8051-TX D306 8-719-422-37 DIODE MA8051-TX D308 8-719-422-37 DIODE MA8051-TX D401 6-500-483-01 DIODE MA22D2800LS0 D402 8-719-085-43 DIODE MA2YD2300LS0 D403 8-719-071-87 DIODE MA785-(TX),SO D404 8-719-071-87 DIODE MA785-(TX),SO D405 8-719-072-70 DIODE MA2ZD14001S0 D406 8-719-404-50 DIODE MA111-TX D804 6-500-781-01 DIODE SML-521MUW (OPR) D805 6-500-473-01 DIODE MA4SD0100LS0 < FERRITE BEAD > FB301 1-414-813-11 FERRITE 0uH FB302 1-414-813-11 FERRITE 0uH FB402 1-216-864-11 METAL CHIP 0 5% 1/16W FB601 1-414-760-21 FERRITE 0uH FB602 1-216-864-11 METAL CHIP 0 5% 1/16W FB603 1-216-864-11 METAL CHIP 0 5% 1/16W FB604 1-414-760-21 FERRITE 0uH FB605 1-216-864-11 METAL CHIP 0 5% 1/16W FB701 1-414-760-21 FERRITE 0uH FB706 1-414-760-21 FERRITE 0uH < IC > IC301 6-705-414-01 IC AN17020B-E1 IC401 6-600-327-01 IC TB2166FG * IC403 6-703-107-01 IC SN74LVC2G66DCUR IC601 8-752-420-71 IC CXD3039AR IC602 6-702-737-01 IC MSM51X17400F-10TFSR1 IC602 6-704-280-01 IC 41SV44052-100TG IC701 6-550-559-01 TRANSISTOR XN0NE9200LS0 IC702 8-753-210-87 IC CXR710160-207R IC801 6-803-671-01 IC TMP91CY28FG-2772-01 ✩ IC802 ---------------- IC AK6417CH-E2 < JACK > J401 1-815-912-21 JACK, DC (EXT BATT) J402 1-815-912-21 JACK, DC (CHARGING STAND) < COIL > L301 1-469-967-21 INDUCTOR 10uH L302 1-400-317-21 INDUCTOR 100uH L401 1-412-056-11 INDUCTOR 4.7uH L402 1-412-056-11 INDUCTOR 4.7uH L403 1-469-967-21 INDUCTOR 10uH L404 1-400-317-21 INDUCTOR 100uH L405 1-414-434-11 INDUCTOR 100uH L406 1-400-145-21 INDUCTOR 47uH L407 1-400-145-21 INDUCTOR 47uH L408 1-419-188-41 INDUCTOR 100uH ✩When IC802 is damaged, replace the MAIN board. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks 33 D-NE10 MAIN L409 1-414-434-11 INDUCTOR 100uH L410 1-400-145-21 INDUCTOR 47uH L411 1-428-912-21 INDUCTOR 10uH L412 1-419-949-21 INDUCTOR 22uH L604 1-400-145-21 INDUCTOR 47uH L605 1-469-967-21 INDUCTOR 10uH L702 1-469-846-11 INDUCTOR 47uH L703 1-469-846-11 INDUCTOR 47uH < TRANSISTOR > Q301 8-729-039-13 TRANSISTOR BCR119W-GEG-E6327 Q302 8-729-922-10 TRANSISTOR 2SA1577-T106-QR Q303 8-729-039-13 TRANSISTOR BCR119W-GEG-E6327 Q304 8-729-028-86 TRANSISTOR DTA143EUA-T106 Q401 6-550-760-01 TRANSISTOR 2SA1363-T111-1E Q401 8-729-807-34 TRANSISTOR 2SB1188-T100-QR Q402 6-550-364-01 TRANSISTOR 2SD2652T106 Q403 8-729-056-57 TRANSISTOR TPC6201(TE85L) Q404 8-729-056-57 TRANSISTOR TPC6201(TE85L) Q405 8-729-028-74 TRANSISTOR DTA114TUA-T106 Q406 8-729-602-36 TRANSISTOR 2SA1602TP-1EF Q801 8-729-427-72 TRANSISTOR XP4501-TXE Q803 8-729-427-49 TRANSISTOR XP4214-TXE Q804 8-729-929-02 TRANSISTOR DTC124XE-TL < RESISTOR > R101 1-208-715-11 METAL CHIP 22K 0.5% 1/16W R102 1-208-715-11 METAL CHIP 22K 0.5% 1/16W R103 1-218-937-11 RES-CHIP 47 5% 1/16W R104 1-218-965-11 RES-CHIP 10K 5% 1/16W R105 1-500-234-22 FERRITE 0uH R106 1-220-803-81 RES-CHIP 4.7 5% 1/16W R109 1-218-990-11 SHORT CHIP 0 R201 1-208-715-11 METAL CHIP 22K 0.5% 1/16W R202 1-208-715-11 METAL CHIP 22K 0.5% 1/16W R203 1-218-937-11 RES-CHIP 47 5% 1/16W R204 1-218-965-11 RES-CHIP 10K 5% 1/16W R205 1-500-234-22 FERRITE 0uH R206 1-220-803-81 RES-CHIP 4.7 5% 1/16W R209 1-218-990-11 SHORT CHIP 0 R301 1-218-965-11 RES-CHIP 10K 5% 1/16W R302 1-218-989-11 RES-CHIP 1M 5% 1/16W R303 1-218-989-11 RES-CHIP 1M 5% 1/16W R304 1-218-969-11 RES-CHIP 22K 5% 1/16W R307 1-208-935-11 METAL CHIP 100K 0.5% 1/16W R309 1-208-943-11 METAL CHIP 220K 0.5% 1/16W R310 1-218-990-11 SHORT CHIP 0 R311 1-218-990-11 SHORT CHIP 0 R312 1-218-965-11 RES-CHIP 10K 5% 1/16W R313 1-218-965-11 RES-CHIP 10K 5% 1/16W R314 1-208-707-11 METAL CHIP 10K 0.5% 1/16W R315 1-218-953-11 RES-CHIP 1K 5% 1/16W R316 1-218-953-11 RES-CHIP 1K 5% 1/16W R317 1-216-864-11 METAL CHIP 0 5% 1/16W R318 1-414-813-11 FERRITE 0uH R401 1-218-941-81 RES-CHIP 100 5% 1/16W R402 1-244-387-91 RES-CHIP 0.22 1% 1/4W R403 1-218-945-11 RES-CHIP 220 5% 1/16W R404 1-208-943-11 METAL CHIP 220K 0.5% 1/16W R405 1-208-927-11 METAL CHIP 47K 0.5% 1/16W R406 1-218-973-11 RES-CHIP 47K 5% 1/16W R407 1-218-973-11 RES-CHIP 47K 5% 1/16W R408 1-216-864-11 METAL CHIP 0 5% 1/16W R409 1-216-864-11 METAL CHIP 0 5% 1/16W R410 1-218-965-11 RES-CHIP 10K 5% 1/16W R411 1-216-797-11 METAL CHIP 10 5% 1/16W R412 1-218-977-11 RES-CHIP 100K 5% 1/16W R413 1-218-989-11 RES-CHIP 1M 5% 1/16W R415 1-218-977-11 RES-CHIP 100K 5% 1/16W R416 1-218-989-11 RES-CHIP 1M 5% 1/16W R417 1-218-965-11 RES-CHIP 10K 5% 1/16W R418 1-218-981-11 RES-CHIP 220K 5% 1/16W R419 1-218-990-11 SHORT CHIP 0 R420 1-216-864-11 METAL CHIP 0 5% 1/16W R422 1-216-864-11 METAL CHIP 0 5% 1/16W R423 1-216-864-11 METAL CHIP 0 5% 1/16W R424 1-216-864-11 METAL CHIP 0 5% 1/16W R425 1-216-864-11 METAL CHIP 0 5% 1/16W R426 1-216-864-11 METAL CHIP 0 5% 1/16W R427 1-218-990-11 SHORT CHIP 0 R428 1-218-985-11 METAL CHIP 470K 0.5% 1/16W R429 1-218-989-11 METAL CHIP 1M 0.5% 1/16W R430 1-218-989-11 RES-CHIP 1M 5% 1/16W R431 1-208-943-11 METAL CHIP 220K 0.5% 1/16W R432 1-208-927-11 METAL CHIP 47K 0.5% 1/16W R433 1-218-990-11 SHORT CHIP 0 R434 1-218-965-11 RES-CHIP 10K 5% 1/16W R436 1-218-965-11 RES-CHIP 10K 5% 1/16W R437 1-218-961-11 RES-CHIP 4.7K 5% 1/16W R438 1-218-969-11 RES-CHIP 22K 5% 1/16W R439 1-220-804-11 RES-CHIP 2.2M 5% 1/16W R440 1-218-965-11 RES-CHIP 10K 5% 1/16W R441 1-216-295-91 SHORT CHIP 0 R442 1-218-965-11 RES-CHIP 10K 5% 1/16W R444 1-218-989-11 RES-CHIP 1M 5% 1/16W R445 1-218-973-11 RES-CHIP 47K 5% 1/16W R446 1-218-990-11 SHORT CHIP 0 R447 1-216-864-11 METAL CHIP 0 5% 1/16W R448 1-216-864-11 METAL CHIP 0 5% 1/16W R449 1-208-715-11 METAL CHIP 22K 0.5% 1/16W R450 1-218-989-11 RES-CHIP 1M 5% 1/16W R451 1-208-715-11 METAL CHIP 22K 0.5% 1/16W R452 1-218-985-11 METAL CHIP 470K 0.5% 1/16W R453 1-208-927-11 METAL CHIP 47K 0.5% 1/16W R454 1-218-977-11 RES-CHIP 100K 5% 1/16W R455 1-216-864-11 METAL CHIP 0 5% 1/16W R456 1-218-989-11 RES-CHIP 1M 5% 1/16W R457 1-216-864-11 METAL CHIP 0 5% 1/16W R458 1-218-985-11 RES-CHIP 470K 5% 1/16W R459 1-218-989-11 RES-CHIP 1M 5% 1/16W R460 1-218-973-11 RES-CHIP 47K 5% 1/16W R461 1-218-985-11 RES-CHIP 470K 5% 1/16W R462 1-218-989-11 RES-CHIP 1M 5% 1/16W R602 1-218-969-11 RES-CHIP 22K 5% 1/16W R603 1-218-973-11 RES-CHIP 47K 5% 1/16W R604 1-218-973-11 RES-CHIP 47K 5% 1/16W R605 1-218-969-11 RES-CHIP 22K 5% 1/16W R606 1-218-969-11 RES-CHIP 22K 5% 1/16W R608 1-218-957-11 RES-CHIP 2.2K 5% 1/16W R609 1-218-990-11 SHORT CHIP 0 R610 1-218-969-11 RES-CHIP 22K 5% 1/16W www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks 34 D-NE10 The components identified by mark 0 or dotted line with mark 0 are critical for safety. Replace only with part number specified. Les composants identifiés par une marque 0 sont critiques pour la sécurité. Ne les remplacer que par une pièce portant le numéro spécifié. MAIN R611 1-218-969-11 RES-CHIP 22K 5% 1/16W R612 1-218-977-11 RES-CHIP 100K 5% 1/16W R613 1-218-957-11 RES-CHIP 2.2K 5% 1/16W R614 1-218-989-11 RES-CHIP 1M 5% 1/16W R615 1-218-985-11 RES-CHIP 470K 5% 1/16W R616 1-218-977-11 RES-CHIP 100K 5% 1/16W R618 1-218-977-11 RES-CHIP 100K 5% 1/16W R620 1-218-973-11 RES-CHIP 47K 5% 1/16W R623 1-218-965-11 RES-CHIP 10K 5% 1/16W R624 1-218-981-11 RES-CHIP 220K 5% 1/16W R625 1-218-965-11 RES-CHIP 10K 5% 1/16W R628 1-218-990-11 SHORT CHIP 0 R629 1-218-990-11 SHORT CHIP 0 R630 1-218-937-11 RES-CHIP 47 5% 1/16W R631 1-218-965-11 RES-CHIP 10K 5% 1/16W R633 1-218-990-11 SHORT CHIP 0 R634 1-218-990-11 SHORT CHIP 0 R635 1-218-990-11 SHORT CHIP 0 R636 1-218-990-11 SHORT CHIP 0 R637 1-218-990-11 SHORT CHIP 0 R638 1-218-949-11 RES-CHIP 470 5% 1/16W R639 1-218-990-11 SHORT CHIP 0 R640 1-218-969-11 RES-CHIP 22K 5% 1/16W R641 1-218-965-11 RES-CHIP 10K 5% 1/16W R642 1-218-945-11 RES-CHIP 220 5% 1/16W R643 1-218-990-11 SHORT CHIP 0 R644 1-216-797-11 METAL CHIP 10 5% 1/16W R645 1-218-990-11 SHORT CHIP 0 R701 1-216-864-11 METAL CHIP 0 5% 1/16W R702 1-218-989-11 RES-CHIP 1M 5% 1/16W R703 1-218-990-11 SHORT CHIP 0 R704 1-218-990-11 SHORT CHIP 0 R705 1-218-989-11 RES-CHIP 1M 5% 1/16W R707 1-218-985-11 RES-CHIP 470K 5% 1/16W R708 1-218-977-11 RES-CHIP 100K 5% 1/16W R710 1-218-990-11 SHORT CHIP 0 R712 1-218-945-11 RES-CHIP 220 5% 1/16W R713 1-218-965-11 RES-CHIP 10K 5% 1/16W R717 1-218-977-11 RES-CHIP 100K 5% 1/16W R718 1-218-989-11 RES-CHIP 1M 5% 1/16W R725 1-218-965-11 RES-CHIP 10K 5% 1/16W R801 1-218-977-11 RES-CHIP 100K 5% 1/16W R802 1-208-707-11 METAL CHIP 10K 0.5% 1/16W R803 1-208-707-11 METAL CHIP 10K 0.5% 1/16W R805 1-208-707-11 METAL CHIP 10K 0.5% 1/16W R806 1-218-977-11 RES-CHIP 100K 5% 1/16W R807 1-218-977-11 RES-CHIP 100K 5% 1/16W R811 1-218-981-11 RES-CHIP 220K 5% 1/16W R812 1-218-977-11 RES-CHIP 100K 5% 1/16W R813 1-218-990-11 SHORT CHIP 0 R824 1-218-961-11 RES-CHIP 4.7K 5% 1/16W R826 1-218-949-11 RES-CHIP 470 5% 1/16W R827 1-218-990-11 SHORT CHIP 0 R828 1-218-990-11 SHORT CHIP 0 R829 1-218-977-11 RES-CHIP 100K 5% 1/16W R830 1-218-989-11 RES-CHIP 1M 5% 1/16W R831 1-218-985-11 RES-CHIP 470K 5% 1/16W R832 1-218-965-11 RES-CHIP 10K 5% 1/16W R835 1-220-804-11 RES-CHIP 2.2M 5% 1/16W R836 1-218-989-11 RES-CHIP 1M 5% 1/16W R840 1-218-990-11 SHORT CHIP 0 R841 1-218-989-11 RES-CHIP 1M 5% 1/16W R846 1-218-990-11 SHORT CHIP 0 R848 1-414-760-21 FERRITE 0uH R857 1-218-965-11 RES-CHIP 10K 5% 1/16W R858 1-218-945-11 RES-CHIP 220 5% 1/16W R859 1-218-957-11 RES-CHIP 2.2K 5% 1/16W R860 1-218-961-11 RES-CHIP 4.7K 5% 1/16W R861 1-218-965-11 RES-CHIP 10K 5% 1/16W R862 1-218-990-11 SHORT CHIP 0 R863 1-218-961-11 RES-CHIP 4.7K 5% 1/16W R864 1-218-969-11 RES-CHIP 22K 5% 1/16W R865 1-218-953-11 RES-CHIP 1K 5% 1/16W R867 1-218-961-11 RES-CHIP 4.7K 5% 1/16W R868 1-218-973-11 RES-CHIP 47K 5% 1/16W R869 1-218-957-11 RES-CHIP 2.2K 5% 1/16W R871 1-218-957-11 RES-CHIP 2.2K 5% 1/16W < VARIABLE RESISTOR > RV401 1-227-412-21 RES, ADJ, CERMET 47K < SWITCH > S802 1-572-922-11 SWITCH, SLIDE (> HOLD) S803 1-786-650-21 SWITCH, TACTILE (u) S804 1-786-650-21 SWITCH, TACTILE (>) S805 1-786-650-21 SWITCH, TACTILE (.) S806 1-786-650-21 SWITCH, TACTILE ( +) S807 1-786-650-21 SWITCH, TACTILE ( -) S808 1-786-650-21 SWITCH, TACTILE (VOL +) S809 1-786-650-21 SWITCH, TACTILE (VOL -) S811 1-786-650-21 SWITCH, TACTILE (x) S812 1-786-680-21 SWITCH, DETECTION (SMD)(OPEN/CLOSE) < VARISTOR > VDR302 1-801-862-11 VARISTOR, CHIP (1608) VDR401 1-801-862-11 VARISTOR, CHIP (1608) VDR601 1-801-862-11 VARISTOR, CHIP (1608) VDR603 1-801-862-11 VARISTOR, CHIP (1608) VDR604 1-801-862-11 VARISTOR, CHIP (1608) VDR605 1-801-862-11 VARISTOR, CHIP (1608) VDR606 1-801-862-11 VARISTOR, CHIP (1608) VDR703 1-801-862-11 VARISTOR, CHIP (1608) VDR704 1-801-862-11 VARISTOR, CHIP (1608) VDR802 1-801-862-11 VARISTOR, CHIP (1608) VDR803 1-801-862-11 VARISTOR, CHIP (1608) VDR804 1-801-862-11 VARISTOR, CHIP (1608) VDR805 1-801-862-11 VARISTOR, CHIP (1608) < VIBRATOR > X601 1-795-003-22 VIBRATOR, CRYSTAL 16.934MHz X701 1-795-392-41 VIBRATOR, CERAMIC 22MHz ************************************************************ MISCELLANEOUS *************** 0102 X-3380-950-1 OPTICAL PICK-UP (DAX-25E) ************************************************************ www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks 35 D-NE10 ACCESSORIES ************ 1-417-397-11 CHARGE BOARD 1-417-423-11 BATTERY CASE (EBP-16) 0 1-477-562-21 ADAPTOR, AC (AC-ES305K)(JE) 0 1-477-563-41 ADAPTOR, AC (AC-ES305K)(KR) 0 1-477-568-41 ADAPTOR, AC (AC-ES305K)(AUS) 1-477-573-22 REMOTE COMMANDER (RM-MC33EL) 0 1-478-424-11 ADAPTOR, AC (AC-ES3010K)(CH) 0 1-478-425-31 ADAPTOR, AC (AC-ES3010K)(AEP,EE,E18) 0 1-478-426-31 ADAPTOR, AC (AC-ES3010K)(UK,HK) 0 1-478-426-41 ADAPTOR, AC (AC-ES3010K)(EA) 0 1-478-427-11 ADAPTOR, AC (AC-ES3010K)(CND) 0 1-478-427-21 ADAPTOR, AC (AC-ES3010K)(US,TW) 1-756-120-23 BATTERY, NICKEL HYDROGEN (AEP,UK,AUS,CH,JE,EE,HK,E18,KR,EA) 1-756-120-32 BATTERY, NICKEL HYDROGEN (US,CND) 3-008-521-01 CASE, BATTERY CHARGE 3-235-292-02 POUCH, CARRYING 3-266-251-13 MANUAL, INSTRUCTION (ENGLISH)(EXCEPT EA) 3-266-251-23 MANUAL, INSTRUCTION (SPANISH,PORTUGUESE,FRENCH)(CND,AEP) 3-266-251-33 MANUAL, INSTRUCTION (DUTCH,GERMAN,ITALIAN)(AEP) 3-266-251-43 MANUAL, INSTRUCTION (SWEDISH,FINNISH)(AEP) 3-266-251-52 MANUAL, INSTRUCTION (HUNGARIAN,RUSSIAN,POLISH)(EE) 3-266-251-62 MANUAL, INSTRUCTION (CZECH,SLOVAK)(EE) 3-266-251-72 MANUAL, INSTRUCTION (TRADITIONAL CHINESE,SIMPLIFIED CHINESE,KOREAN) (CH,JE,HK,TW,E18,KR) 3-266-251-82 MANUAL, INSTRUCTION (ARABIC)(EA) 3-266-251-92 MANUAL, INSTRUCTION (ENGLISH)(EA) 3-258-820-11 MANUAL, INSTRUCTION (SonicStage Simple Burner)(ENGLISH) (US,CND,AEP,UK,AUS,EE) 3-258-820-21 MANUAL, INSTRUCTION (SonicStage Simple Burner) (SPANISH,PORTUGUESE,FRENCH)(CND,AEP) 3-258-820-31 MANUAL, INSTRUCTION (SonicStage Simple Burner) (DUTCH,GERMAN,ITALIAN)(AEP) 3-258-820-41 MANUAL, INSTRUCTION (SonicStage Simple Burner)(SWEDISH,FINNISH)(AEP) 3-258-820-51 MANUAL, INSTRUCTION (SonicStage Simple Burner)(HUNGARIAN, RUSSIAN,POLISH)(EE) 3-258-820-61 MANUAL, INSTRUCTION (SonicStage Simple Burner)(CZECH,SLOVAK)(EE) 3-258-820-71 MANUAL, INSTRUCTION (SonicStage Simple Burner)(TRADITIONAL CHINESE, SIMPLIFIED CHINESE,KOREAN)(JE,KR) 3-258-821-11 MANUAL, INSTRUCTION (CH,JE,HK,TW,E18) 8-953-218-91 RECEIVER MDR-E838SP/SK SET (CND,AEP,UK,AUS,CH,JE,EE,HK,TW,E18,KR) X-3384-249-1 CD-ROM (APPLICATION) ASSY (SonicStage Simple Burner)(US,CND) X-3384-250-1 CD-ROM (APPLICATION) ASSY (SonicStage Simple Burner)(AEP,UK,EE) X-3384-251-1 CD-ROM (APPLICATION) ASSY (SonicStage Simple Burner)(AUS,CH,HK,TW,E18,KR) X-3384-252-1 CD-ROM (APPLICATION) ASSY (SonicStage Simple Burner)(JE) X-3384-677-1 CD-ROM (APPLICATION) ASSY (SonicStage Simple Burner)(EA) The components identified by mark 0 or dotted line with mark 0 are critical for safety. Replace only with part number specified. Les composants identifiés par une marque 0 sont critiques pour la sécurité. Ne les remplacer que par une pièce portant le numéro spécifié. Ver 1.2 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com D-NE10 REVISION HISTORY Clicking the version allows you to jump to the revised page. Also, clicking the version at the upper right on the revised page allows you to jump to the next revised page. Ver. Date Description of Revision 1.0 2003.11 New 1.1 2004.03 Addition of Part No. for LID ASSY (UPPER), change of Part No. for Ref No. 2 and 3 (SPM-04017) 1.2 2004.03 Addition of Saudi Arabia model (SPM-04029) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com
