1 Model Name Using Similar Mechanism D-E220/E225/E226CK CD Mechanism Type CDM-3123EBA Optical Pick-up Name DAX-23E SERVICE MANUAL US Model D-F20 FM/AM PORTABLE CD PLAYER CD player System Compact disc digital audio system Laser diode properties Material: GaAlAs Wavelength: λ = 780 nm Emission duration: Continuous Laser output: Less than 44.6 µW (This output is the value measured at a distance of 200 mm from the objective lens surface on the optical pick-up block with 7 mm aperture.) D-A conversion 1-bit quartz time-axis control Frequency response 20 - 20,000 Hz +1/–2 dB (measured by EIAJ CP-307) Output (at 4.5 V input level) Headphones (stereo minijack) Approx. 12 mW + Approx. 12 mW at 16 ohms SPECIFICATIONS Radio Frequency range (STEP switch) 9 kHz step: FM: 87.5 - 108.0 MHz AM: 531 - 1,710 kHz 10 kHz step: FM: 87.5 - 108.0 MHz AM: 530 - 1,710 kHz Antenna FM: Headphones cord antenna AM: Built-in ferrite bar antenna General Power requirements For the area code of the model you purchased, check the upper left side of the bar code on the package. • Two LR6 (size AA) batteries: 3 V DC • AC power adaptor (DC IN 4.5 V jack): 120 V, 60Hz Battery life* (approx. hours) (When you use the CD player on a flat and stable surface.) Playing time varies depending on how the CD player is used. When using ESP RADIO on off on Two sony alkaline 24 25 66 batteries LR6(SG) * Measured value by the standard of JEITA (Japan Electronics and Information Technology Industries Association). ** Charging time varies depending on how the rechargeable battery is used. Operating temperature 5°C - 35°C (41°F - 95°F) Dimensions (w/h/d) (excluding projecting parts and controls) Approx. 161 × 26.3 × 130.3 mm (6 3/8 × 1 1/16 × 5 1/4 in.) Mass (excluding accessories) Approx. 210 g (7.5 oz.) Supplied accessories For the area code of the location in which you purchased the CD player, check the upper left side of the bar code on the package. Headphones (1) Design and specifications are subject to change without notice. Ver 1.0 2001.05 9-873-148-01 2001E0400-1 © 2001.5 Sony Corporation Personal Audio Company Shinagawa Tec Service Manual Production Group www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 2 Flexible Circuit Board Repairing • Keep the temperature of the soldering iron around 270°C during repairing. • Do not touch the soldering iron on the same conductor of the circuit board (within 3 times). • Be careful not to apply force on the conductor when soldering or unsoldering. Notes on Chip Component Replacement • Never reuse a disconnected chip component. • Notice that the minus side of a tantalum capacitor may be damaged by heat. TABLE OF CONTENTS 1. SERVICE NOTE................................................................. 3 2. GENERAL Getting started ......................................................................... 4 3. DISASSEMBLY 3-1. “Lid, Battery Case”, Cabinet (Front) Assy.......................... 5 3-2. Lid Assy, Upper ................................................................... 5 3-3. Main Board, MD Assy ........................................................ 6 3-4. Optical Pick-up, Motor ....................................................... 6 4. ELECTRICAL ADJUSTMENTS Tuner Section........................................................................... 7 CD Section .............................................................................. 8 5. DIAGRAMS 5-1. IC Pin Descriptions ............................................................. 9 5-2. Block Diagram –CD Section–........................................... 13 5-3. Block Diagram –Tuner Section– ....................................... 14 5-4. Block Diagram –Power Supply Section– .......................... 15 5-5. Printed Wiring Board –Main Section– .............................. 16 5-6. Schematic Diagram –Main Section (1/3)– ......................... 18 5-7. Schematic Diagram –Main Section (2/3)– ......................... 19 5-8. Schematic Diagram –Main Section (3/3)– ......................... 20 5-9. IC Block Diagrams............................................................ 21 6. EXPLODED VIEWS 6-1. Cabinet (Front) Section ..................................................... 24 6-2. Cabinet (Lower) Section ................................................... 25 6-3. CD Mechanism Deck Section (CDM-3123EBA) ............. 26 7. ELECTRICAL PARTS LIST......................................... 27 D-F20 SAFETY-RELATED COMPONENT WARNING!! COMPONENTS IDENTIFIED BY MARK 0 OR DOTTED LINE WITH MARK 0 ON THE SCHEMATIC DIAGRAMS AND IN THE PARTS LIST ARE CRITICAL TO SAFE OPERATION. REPLACE THESE COMPONENTS WITH SONY PARTS WHOSE PART NUMBERS APPEAR AS SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUBLISHED BY SONY. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 3 D-F20 SOUND/ PRESET – S811 L3 AM FERRITE- ROD ANTENNA S801 CD DOOR OPEN S801 – MAIN BOARD (SIDE B) – RF-IN TAP802 – MAIN BOARD (SIDE A) – SECTION 1 SERVICE NOTE NOTES ON HANDLING THE OPTICAL PICK-UP BLOCK OR BASE UNIT The laser diode in the optical pick-up block may suffer electro- static breakdown because of the potential difference generated by the charged electrostatic load, etc. on clothing and the human body. During repair, pay attention to electrostatic breakdown and also use the procedure in the printed matter which is included in the repair parts. The flexible board is easily damaged and should be handled with care. Precautions for Checking Emission of Laser Diode Laser light of the equipment is focused by the object lens in the optical pick-up so that the light focuses on the reflection surface of the disc. Therefore, be sure to keep your eyes more then 30 cm apart from the object lens when you check the emission of laser diode. Before Replacing the Optical Pick-Up Block Please be sure to check throughly the parameters as par the “Opti- cal Pick-Up Block Checking Procedures” (Part No.: 9-960-027- 11) issued separately before replacing the optical pick-up block. Note and specifications required to check are given below. • FOK output : IC601 eg pin When checking FOK, remove the lead wire to disc motor. • RF signal P-to-P value : 0.45 ± 0.1 Vp-p • The repairing grating holder is impossible. Laser Diode Checking Methods During normal operation of the equipment, emission of the laser diode is prohibited unless the upper lid is closed while turning ON the S801. (push switch type) The following two checking methods for the laser diode are operable. • Method: Emission of the laser diode is visually checked. 1. Open the upper lid. 2. With a disc not set, turn on the S801 with a screwdriver having a thin tip as shown in Fig.1. or TAP802 is shorted as shown in Fig.2. Note: Do not push the detection lever strongly, or it may be bent or damaged. 3. Press the N X button. 4. Observing the objective lens, check that the laser diode emits light. When the laser diode does not emit light, automatic power control circuit or optical pick-up is faulty. In this operation, the objective lens will move up and down 5 times along with inward motion for the focus search. detection lever detection lever main board S801 Fig. 2 Fig. 1 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 4 D-F20 SECTION 2 GENERAL This section is extracted from instruction manual. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 5 D-F20 Note : Follow the disassembly procedure in the numerical order given. 3-2. LID ASSY, UPPER SECTION 3 DISASSEMBLY 3-1. “LID, BATTERY CASE”, CABINET (FRONT) ASSY 1 B 2x10 3 B 2x10 4 claws 0 cabinet (upper) assy 5 claws 6 claws 7 claws 8 9 2 lid, battery case boss 1 claws 2 lid assy, upper cabinet (front) assy www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 6 D-F20 3-3. MAIN BOARD, MD ASSY 3-4. OPTICAL PICK-UP, MOTOR 1 CN501 4 MD assy 7 MAIN board cabinet (lower) sub assy knob (HOLD) terminal (+.–), battery (BT400) terminal (–), battery (BT402) S803 2 CN502 5 S812 6 S813 3 CN503 1 B 1.7x5 3 B 1.7x5 7 P 1.4x3.5 9 B 1.4x2.3 0 rack 8 retainer, shaft qa screw (feed) assy qd shaft, standard qs pick-up block, optical 4 cover, gear 2 motor assy, turntable (M502) 5 motor assy, sled (M501) chassis 6 gear (B) Note: When installing, fit the knob (HOLD) and S803. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 7 D-F20 digital voltmeter 100 kΩ TP81 (VT) i jack (J302) set 16 Ω level meter (range: 0.5–5 V ac) Put the lead-wire antenna close to the set. AM RF signal generator TP3 (RF-IN) FM RF signal generator 0.01 µF set TUNER SECTION 0 dB = 1 µV • FM Section Setting: RADIO ON•BAND/MEMORY button : FM STEP switch : 10k 75 kHz frequency deviation by 1 kHz signal output level : as low as possible • AM Section Setting: RADIO ON•BAND/MEMORY button : AM STEP switch : 10k 30% amplitude modulation by 400 Hz signal • Connecting Level Meter (FM and AM) • Connecting Digital Voltmeter (FM and AM) • Repeat the procedures in each adjustment several times, and the frequency coverage and tracking adjustments should be finally done by the trimmer capacitors. • For FM adjustment, fix the FM RF coil (L1) as shown next page and then perform tracking adjustment at L2 and CT1. Lastly check the voltage value. • For AM adjustment, fix the ferrite-rod antenna (L3) as shown next page and then perform tracking adjustment at L4 and CT3. Lastly check the voltage value. Adjustment Location: See page 8. SECTION 4 ELECTRICAL ADJUSTMENTS FM FREQUENCY COVERAGE CHECK Frequency Display 87.5 MHz 108 MHz Reading on Digital voltmeter 2.5 ± 1.5 V 7.0 ± 4.0 V Adjustment Part FM TRACKING ADJUSTMENT Adjust for a maximum reading on level meter. L2 CT1 87.5 MHz 108 MHz AM IF ADJUSTMENT Adjust for a maximum reading on level meter. T1 450 kHz AM FREQUENCY COVERAGE CHECK Frequency Display 530 kHz 1,710 kHz Reading on Digital voltmeter 1.0 ± 0.5 V 5.2 ± 0.7 V Adjustment Part AM TRACKING ADJUSTMENT Adjust for a maximum reading on level meter. L4 CT3 620 kHz 1,400 kHz www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 8 D-F20 TP629 RF – MAIN BOARD (SIDE B) – Adjustment Location: CD SECTION CD section adjustments are done automatically in this set. In case of operation check, confirm that focus bias. FOCUS BIAS CHECK 1. Connect the oscilloscope between TP629 (RF) and GND on main board. 2. Insert the disc (YEDS-18). (Part No. : 3-702-101-01) 3. Press the N X button. 4. Confirm that the oscilloscope waveform is as shown in the figure below. (eye pattern) A good eye pattern means that the diamond shape ( ) in the center of the waveform can be clearly distinguished. • RF signal reference waveform (eye pattern) Test Point: When observing the eye pattern, set the oscilloscope for AC range and raise vertical sensitivity. CN501 IC61 TP81 VT TP3 RF-IN – MAIN BOARD (SIDE A) – CT3 L4 L3 L1 CT1 L2 FM TRACKING ADJ AM IF ADJ T1 AM TRACKING ADJ RF level : 0.45 ± 0.1 Vp-p VOLT/DIV : 20 mV (10 : 1 probe in use) TIME/DIV : 500 nS www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 9 D-F20 SECTION 5 DIAGRAMS 5-1. IC PIN DESCRIPTIONS • IC61 TC9327AF-631 (TUNER PLL, LCD DRIVER) Pin No. Pin Name I/O Pin Description 1 – 4 COM1 – 4 O LCD driver signal output 5 – 20 S1 – 16 O LCD driver signal output 21 AM STEP-I I AM 9K/10K tuning step select signal input (initialization) 22 DEST2-I I Bit2 tuner destination setting signal input (Fixed at “L” in this set) 23 DEST1-I I Bit1 tuner destination setting signal input (Fixed at “L” in this set) 24 DEST0-I I Bit0 tuner destination setting signal input (Fixed at “L” in this set) 25 XLOCAL/XMONO-DET-I I LOCAL/DX or MONO/STEREO ON-OFF switch detect signal input 26, 27 NC — Not used. (Open) 28 LCDREQ-I I LCD display request signal input 29 LID OPEN I CD door open detect signal input 30 EEP D0/D1-IO I/O Data signal input/output for EEPROM IC. 31 EEP SK-O O Clock signal output for EEPROM IC. 32 EEP CS-O O Chip select signal output for EEPROM IC. 33 XL/O-I I Line out signal input 34, 35 NC — Not used. (Open) 36 MEM-KEY (3-BIT) I Memory key signal input (Fixed at “H” in this set) 37 PRESET KEY I Not used in this set. (Open) 38 CD ACK-I O CD acknowledge signal output 39 CDON-IWP-CDU I CD ON request signal input (Wake-up tuner in sleep mode) 40 I/O (RESERVED) — Not used. (Open) 41 NC — Not used. (Open) 42 AD1 KEY I Set keys signal input 43 AD2 RMKEY I Remote key signal input (Fixed at “L” in this set) 44 AD3 BATT HIDC I Battery/HiDC level detect signal input 45 AD DC REF I Reference DC signal input of A/D. 46 SDI-I-CDU I Serial data signal input from system control IC. 47 SDO-O-CDU (RESERVED) O Serial data signal output to system control IC. 48 SCK-I-CDU I Serial clock signal input from system control IC. 49 TUBEEP-O O Beep sound control signal output 50 NC (I/O) — Not used. (Open) 51 XHOLD-I-SW I HOLD detect signal input 52 XAVLS-I-SW I AVLS detect signal input 53 XDC IN DET-I I DC-in detect signal input 54 TU ON-O O Tuner ON request signal output 55 ST OR DX-O-CTR O LOCAL/DX or MONO/STEREO ON-OFF control signal output 56 TUBASS2-O O MEGA BASS 2 sound mode signal output (Not used in this set) 57 TU TEST MODE I Tuner test mode detect signal input 58 TUBASS1-O O MEGA BASS 1 sound mode signal output (Not used in this set) 59 AM/XFM-O O Band control FM/AM signal output to tuner IC. 60 +B ON/OFF O Radio power ON/OFF signal output 61 IFREQ-O O IF request signal output 62 TUMUTE-O O Mute HP control signal output 63 TEST — Not used. (Open) 64 IFIN I FM/AM IF signal input 65 EO (DO1) O PLL error signal output 66 NC (DO2) — Not used. (Open) 67 HOLD I Not used. (Connect to ground in this set) 68 NC — Not used. (Open) 69 GND — Ground 70 FM IN I FM oscillation signal input www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 10 D-F20 Pin No. Pin Name I/O Pin Description 71 AM IN I AM oscillation signal input 72 VDD (1.8-2.2V) — Power supply pin 73 RESET I Power reset signal input 74 XOUT O Crystal oscillation signal output (75 kHz) 75 XIN I Crystal oscillation signal input (75 kHz) 76 VXT — Crystal oscillation signal pin 77 VLCD — LCD voltage doubler 78, 79 C1, 2 — LCD voltage doubler 80 VEE — Constant voltage output to LCD. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 11 D-F20 • IC801 TMP88CM22AF-Z3TU01 (SYSTEM CONTROL) Pin No. Pin Name I/O Pin Description 1 VSS — Ground 2 PWRSW O Headphone AMP IC power switch signal output 3 FOK I I Focus OK signal input from DSP IC. (“L”: NG, “H”: OK) 4 AGCPWM O O AGC control pulse signal output (Not used in this set) 5 CDON O O CD ON request signal output 6 SWEN2 O O CD/tuner select signal output 7 AMUTE O O Analog audio mute ON/OFF control signal output 8 VCC2ON O — Power supply pin (Not used in this set) 9 XRST O O Reset signal output to DSP IC. 10 SCK O O Serial data transfer clock signal output to DSP IC. 11 (SENS) SDTI I I Serial data signal input from DSP IC. 12 SDTO O O Serial data signal output to DSP IC. 13 SLPOUT O O WAKE-UP control signal output 14 AD CDTEST I CD test signal input (“L”: CD test) (Fixed at “H” in this set) 15 AD CHGMNT I Not used in this set. (Open) 16 AD RMKEY I Not used in this set. (Fixed at “L”) 17 AD BATMNT I Battery voltage detect signal input 18 AD CDKEY I Key signal input 19 AD RM INT I Not used in this set. (Open) 20 AD DCINMNT I DC-in voltage detect signal input (A/D input) and DC-in jack use/no use detect signal input. 21 WP OPEN I CD door open switch signal input 22 VREFL I Reference voltage signal input (0 V) for A/D converter. 23 VREFH I Reference voltage signal input (+2 V) for A/D converter. 24 VDD — Power supply pin (+2 V) 25 SCOR I I Sub-code sync (S0+S1) detect signal input from DSP IC. 26 GRSCOR I I GRSCOR signal input from DSP IC. 27 WFCK I I WFCK signal input from DSP IC. 28 BEEP O O Beep sound signal output to headphone AMP IC. 29 XCDRESET TU O O Reset signal output to DSP IC. 30 TUSCK O O Communication clock signal output to DSP IC. 31 (CD) SDI I I Communication data bus signal input from DSP IC. 32 (CD) SDO O O Communication data bus signal output to DSP IC. 33 RESERVE — Not used. (Open) 34 ACK CD I I CD acknowledge signal input 35 TUON I I Tuner ON request signal input 36 ESP I ESP switch signal input 37 L/O I I Line out signal input 38 AVLS I I AVLS switch signal input 39 HOLD I I HOLD switch signal input 40 CD-RW I Not used in this set. (Open) 41 — — Not used. (Open) 42 XHGON O O Not used in this set. (Open) 43 XTL O O Serial data latch pulse signal output 44 XSOE O O Serial data output enable signal output 45 TUVCPU O O Not used in this set. (Open) 46 POWLT O O Latch signal output to power control IC. 47 TUAUDIO O O Not used in this set. (Open) 48 XAPC OFF O O APC mute signal output (“L”: mute) 49 CDAUDIO O O Not used in this set. (Open) 50 RESERVE — Not used. (Open) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 12 D-F20 Pin No. Pin Name I/O Pin Description 51 BASS1 O O Not used. (Fixed at “H” in this set) 52 BASS2 O O Not used. (Fixed at “H” in this set) 53 LCDREQ O O LCD display request signal output 54 – 64 SEG10 – 0 O Not used in this set. (Open) 65 – 68 COM3 – 0 O Not used in this set. (Open) 69 – 71 V3 – 1 O Not used in this set. (Open) 72, 73 C1, 0 O Not used in this set. (Open) 74 CDWP I I WAKE-UP control signal input 75 ICTEST I Test pin for IC. (Fixed at “L” in this set) 76 — — Not used. (Open) 77 — — Not used. (Fixed at “L” in this set) 78 RESET I I System reset signal input from power control IC. (“L”: reset) 79 XIN I I System clock signal input 80 XOUT O Not used in this set. (Open) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com D-F20 13 13 5-2. BLOCK DIAGRAM — CD SECTION — 1 2 DIGITAL SIGNAL PROCESSOR, DIGITAL SERVO PROCESSOR IC601 13 97 104 94 93 83 78 28 26 30 35 24 25 23 3 27 26 11 44 43 10 12 25 21 LPF SIGNAL PROCESSOR BLOCK MEMORY CONTROLLER, BUS BOOST BLOCK SERVO BLOCK • Signal path : CD PLAY MDS 44 MDS MDP 43 MDP COMP OUT SENS SCOR 17 SCOR 42 11 12 10 C176 SDTO XTAI XTAO RFAC XSOE R4M XLAT CLOK LOUT ROUT AMUTE FOK FOK R4M XSOE WDCK WFCK SDTO SENS CLOK XLAT XSOE_O GRSCOR_I FOK_I WFCK_I SDTO_O SCOR_I (SENS) SDTI_I SCK_O XLAT_O 46 47 SFDR XRST RFDC B A 2 WDCK WFCK XTAO XTAI E F SRDR TRDR FRDR FFDR TFDR FFDR FRDR 59 F 62 61 A B 58 71 RFDC RFAC E 50 51 SFDR SRDR 48 49 35 36 13 14 61 TFDR TRDR OPTICAL PICK-UP BLOCK (DAX-23E) A A CN501 CN503 CN502 B RF E F B RF E F PD PD LD LD DETECTOR VCC FOCUS COIL TRACKING COIL FI2 RI2 33 34 FI1 RI1 FI3 SAW TOOTH MDP VINDET RI3 15 PWM/FI4 16 PDL/RI4 APCREF VCC1 +2V FO2 RO2 FO3 RO3 RF2 INM2 RF21 PAPC F+ F– T+ T– + COMPARATOR IC401 (2/3) SYNC 48 XAPC_OFF_O 9 XRST_O SDTO SCK SYSTEM CONTROL IC801 (1/3) X601 16.9MHz CD-L CD-R A MUTE B C A 60 28 26 23 21 63 64 59 M502 SPINDLE MOTOR FO4 RO4 M C+ C– 19 17 DRIVER DRIVER CONTROLLER DRIVER PD AMP LD AMP LD DRIVER Q403,405 LEVEL SHIFTER 60 FOCUS/TRACKING COIL DRIVER, SPINDLE/SLED MOTOR DRIVE IC401 (1/3) B+ +3V 62 D 115 – 118 113 114 119 120 XRAS XWE XCAS XOE D0-D3 A0-A9 4 10 1-3, 5-7, 106-109 79 XIN_I M501 SLED MOTOR FO1 RO1 M S+ S– 32 30 DRIVER 13 12 11 7 8 6 4 1 2 3 10 9 1 2 MAIN BOARD (1/3) (Page 15) (Page 15) (Page 15) (Page 14) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com D-F20 14 14 5-3. BLOCK DIAGRAM — TUNER SECTION — Signal path : FM : AM : CD PLAY AM OSC AM MIX FM MIX FM OSC AM RF-IN FM RF-IN FM RF-OUT 16 15 12 11 20 22 4 6 7 10 2 21 19 24 T1 CF1 L2 L1 CT1 VCPU+2V XDCDT D1 D2 CT3 D3 L3 AM FERRITE-ROD ANTENNA CT3,L4 AM TRACKING CT1,L2 FM TRACKING BUFFER Q61 AM DET FM DET AF BUFFER DC/DC CONVERTER Q86 IF BUFFER FM MPX MUTE IF CUT R-CH L-OUT R-OUT R-CH VDD+2V R-CH D601 D304 D302 17 FM/AM FRONT-END, IF DET,MPX IC1 TU VCC TU VCC Q3 Q6 Q2 TU VCC L4 CF3 IF CUT TU VCC TU VCC FM OSC AM OSC MIX-OUT AM IF-IN FM IF-IN DET-OUT MPX-IN T1 AM IF LIN HEADPHONE AMP IC302 14 LOUT 8 PWRSW MUTE 19 BEEP ALCDET 17 PW SW BEEP MT SW 20 TUNER/CD SIGNAL SELECT IC303 8 9 12 6 11 IF OSC AMP Q60 LPF Q84,85 5 – 20 1 – 4 LIQUID CRYSTAL DISPLAY PANEL LCD1 COM1 | COM4 S1 | S16 22 23 24 74 75 45 32 31 30 1 2 3 25 55 65 53 71 70 61 64 59 6 7 2 28 21 36 62 49 29 73 54 33 38 39 46 47 48 51 52 42 29 74 37 34 5 32 31 30 39 38 18 21 44 X61 75kHz X1 10.7MHz TU VCC TU VCC ST OR DX-O-CTR XDC IN DET-I EO(DO1) AM IN FM IN 60 +B ON/OFF-O DEST2-I DEST1-I DEST0-I XOUT CS SK DI XIN AD DC REF EEP CS-O EEP SK-O EEP DO/D1-IO XLOCAL/XMONO-DET-I AM STEP-I IFREQ-O IF IN IF-OUT OSC-OUT LPF2(MAX/FM) LPF1(MONO/ST) AM/XFM-O TUMUTE-O TUBEEP-O LID OPEN HOLD AVLS SWEN2_O AMUTE_O PWRSW BEEP_O RESET XCDRESET_TU-O CDWP_I L/O_I ACK_CD_I CDON_O (CD)SDO_O (CD)SDI_I TUSCK_I HOLD_I AVLS_I AD3_BATT_HIDC AD_CDKEY SDI-I-CDU SDO-O-CDU SCK-I-CDU XHOLD-I-SW XAVLS-I-SW AD1_KEY HIGH/BATT TU ON-O XL/O-I CD ACK-I WP_OPEN ESP CDON-IWP-CDU 12 10 13 14 +1.6V REG. IC81 B+ SWITCH Q4,5 B+ +3V VCPU+2V TU VCC S813 (LOCAL/DX) S812 STEP 9k 10k AVLS S802 S801 (CD DOOR OPEN) VCPU+2V OPEN AVLS HOLD NORM LIMIT HOLD S803 OFF ON ESP S804 OFF ON LOCAL DX R-CH A MUTE CD-L CD-R T81 D80 KEY MATRIX S805 - 811 VOLUME RV301 D E F MAIN BOARD (2/3) EEPROM IC62 TU VCC TUNER PLL, LCD DRIVER IC61 OPEN SYSTEM CONTROL IC801 (2/3) J302 i (Page 13) (Page 15) (Page 15) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com D-F20 15 15 5-4. BLOCK DIAGRAM — POWER SUPPLY SECTION — SWITCHING POWER CIRCUIT 2 SWITCHING POWER CIRCUIT 5 CHARGE CONTROL B+ SWITCH Q410 B+ SWITCH Q406 B+ SWITCH Q412 CHARGE SWITCH INTERFACE CLK OR OSC AMP BIAS SAWTOOTH GENERATOR STANDBY REFERENCE GATE Q402 DC IN DETECT Q407 COMPARATOR Q413 SWITCH Q401 45 49 42 5 6 8 7 9 53 38 40 41 1 2 37 CHG ON/OFF BANDGAP REFERENCE (VREF) 4 SYSTEM CONTROL IC801 (3/3) 17 20 58 46 13 POWLT_O SLPOUT_O AD_BATMNT 78 RESET_I AD_DCINMNT VCPU +2V VDD +2V VCC1+2V POWER CONTROL IC401 (3/3) B+ B– WAKE-UP RESET SWITCH Q408,409 J401 DC IN 4.5V ! DTC1D VCPU2 (2.0V) VCPU1 (2.5V) 48 INP1 54 STNG VIN CHGSW RS DCIN RF4 DC IN L4 VG VG 43 VLGO1 SYNC VCC1(2.5V) WAKEUP CLOCK DATA SYNC SCK SDTO LATCH RSTB VREF VCPU1 (2.5V) VCPU2 (2.0V) DRY BATTERY SIZE "AA" (IEC DESIGNATION LR6) 2PCS,3V D407 D801 A B C B+ +3V FOCUS/TRACKING COIL DRIVER SPINDLE/SLED MOTOR DRIVER (IC401) +3V, HEADPHONE AMP (IC302) +3V D405 D406 L408 D401 L412 F E 44 VCC1 Q411 HIGH/BATT XDCDT MAIN BOARD (3/3) (Page 13) (Page 13) (Page 13) (Page 14) (Page 14) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com D-F20 16 16 5-5. PRINTED WIRING BOARD — MAIN SECTION — Common Note on Printed Wiring Boards: • X : parts extracted from the component side. • Y : parts extracted from the conductor side. • a : Through hole. • f : internal component. • : Pattern from the side which enables seeing. Common Note on Schematic Diagram: • All capacitors are in µF unless otherwise noted. pF: µµF 50 WV or less are not indicated except for electrolytics and tantalums. • All resistors are in Ω and 1/4 W or less unless otherwise specified. • % : indicates tolerance. • f : internal component. • C : panel designation. • A : B+ Line. • Total current is measured with CD installed. • Power voltage is dc 4.5 V and fed with regulated dc power supply from external power voltage jack. • Voltages and waveforms are dc with respect to ground in playback mode. no mark : FM ( ) : AM < > : CD ∗ : Impossible to measure • Voltages are taken with a VOM (Input impedance 10 MΩ). Voltage variations may be noted due to normal produc- tion tolerances. • Waveforms are taken with a oscilloscope. Voltage variations may be noted due to normal produc- tion tolerances. • Circled numbers refer to waveforms. • Signal path. F : FM f : AM J : CD Caution: Pattern face side: Parts on the pattern face side seen from the (Side B) pattern face are indicated. Parts face side: Parts on the parts face side seen from the (Side A) parts face are indicated. • Semiconductor Location (Side A) D1 G-4 D80 H-8 D82 H-8 D301 G-2 D302 G-2 D303 F-2 D304 F-2 D408 H-6 D461 H-6 D801 H-6 IC61 I-6 Q84 H-4 Q85 I-4 Q401 G-9 Q402 G-9 Q403 F-2 Q405 E-2 Q412 I-8 Ref. No. Location 1 A B C D E F G H I J 2 3 4 5 6 7 8 9 10 OPTICAL PICK-UP BLOCK (DAX-23E) 1-681-838- 1 BLK 2 WHT M502 SPINDLE MOTOR S803 HOLD 1 BLK 2 WHT M501 SLED MOTOR OFF ON RF-IN Note: The components identified by mark 0 or dotted line with mark 0 are critical for safety. Replace only with part number specified. w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com D-F20 17 17 • Refer to page 16 for Common note on Printed Wiring Board. IC61 uf (XOUT) • Waveforms (CD play mode) 1 0.7Vp-p IC601 ih (LRCK) 2 Q86 C 3 TP629 (RF) 4 2.0Vp-p 5 IC601 of (XTAO) 2.0Vp-p 6 IC801 ul (XIN_1) 3.6Vp-p 0.235µsec 200mV/div 5µsec/div 3.6Vp-p 1V/div 0.2µsec/div 100mV/div 0.5µsec/div 22.5µsec 500mV/div 5µsec/div 16.9MHz 500mV/div 0.02µsec/div 1V/div 0.2µsec/div 1 A B C D E F G H I J 2 3 4 5 6 7 8 9 10 11 LCD1 LIQUID CRYSTAL DISPLAY PANEL DC IN 4.5V J401 ! TUNE + S808 > TUNE – S809 . MENU/ PRESET + S810 SOUND/ PRESET – S811 RADIO ON BAND/MEMORY S806 VOLUME S807 RADIO OFF x S805 NX RV301 L3 AM FERRITE- ROD ANTENNA 1-681-838- DRY BATTERY SIZE "AA" (IEC DESIGNATION LR6) 2PCS,3V LIMIT NORM AVLS ON OFF J302 ESP S813 (LOCAL/DX) LOCAL DX S812 9k 10k STEP S801 CD DOOR OPEN 33 48 16 17 32 64 49 1 IC401 • Semiconductor Location (Side B) D2 H-5 D3 H-3 D401 G-9 D402 E-7 D404 G-9 D405 E-7 D406 H-6 D407 E-6 D409 H-6 D415 E-6 D601 C-5 D602 C-5 IC1 G-5 IC62 I-6 IC81 I-5 IC302 G-2 IC303 G-2 IC401 H-7 Ref. No. Location Ref. No. Location IC601 C-4 IC801 B-6 Q2 G-6 Q3 E-5 Q4 E-6 Q5 D-6 Q6 G-6 Q60 I-5 Q61 I-6 Q86 H-9 Q406 D-7 Q407 E-7 Q408 H-6 Q409 H-6 Q410 E-6 Q411 G-8 Q413 E-7 75kHz 34nsec 0.45Vp-p w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com D-F20 18 18 5-6. SCHEMATIC DIAGRAM — MAIN SECTION (1/3) — • Refer to page 17 for Waveforms. • Refer to page 21 for IC Block Diagrams. • Refer to page 16 for Common Note on Schematic Diagram. IC B/D 15 631 68 2SC4116YG-TE85L (Page 19) (Page 20) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com D-F20 19 19 5-7. SCHEMATIC DIAGRAM — MAIN SECTION (2/3) — • Refer to page 17 for Waveforms. • Refer to page 21 for IC Block Diagrams. • Refer to page 16 for Common Note on Schematic Diagram. IC B/D IC B/D 4.7 4.7 10 (Page 20) (Page 18) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com D-F20 20 20 IC B/D 0 0 5-8. SCHEMATIC DIAGRAM — MAIN SECTION (3/3) — • Refer to page 17 for Waveforms. • Refer to page 22 for IC Block Diagrams. • Refer to page 16 for Common Note on Schematic Diagram. (Page 19) (Page 18) w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 21 D-F20 IC1 TA2149BFN 5-9. IC BLOCK DIAGRAMS RF GND 3 2 1 IF REQ AM MIX FM IN AM L/CUT 5 4 MIX OUT VCC AF IF 8 7 6 FM IF GND 10 9 AGC QUAD 12 11 R-OUT L-OUT FM RF 22 23 24 20 21 17 18 19 15 16 13 14 AM RF RF VCC FM OSC XST DET OSC OUT AM OSC XIFREQ LPF1 XMO/ST MPX IN DET OUT LPF2 XAM/FM FM MIX FM OSC LEVEL DET AM DET MUTE FM DET ST/MO FM/AM AM OSC AGC SW ST 1/8 BUFF BUFF DIVIDE DECODE VCO IF BUFF AF BUFF AF FM RF AM IF FM IF 1/1 OR 1/16 + – + – + – 23 18 17 16 15 14 13 2 3 4 5 6 7 8 9 11 12 1 24 BIAS BEEP PW SW MT SW ALC DET ATT SW PWC SW ROUT LOUT BEEP MUTE MUTE_γ BST PW B PW C BST NF ADD OUT RF IN OCL SW ROUT VREF LOUT PGND MIX OUT ALC IN ALC DET ATT SW LIN RIN GND PWR SW BIAS BIAS IN BB SW BST OUT VCC ADDA ADDB 21 22 PW A ALC ALC 20 19 10 IC302 TA2120FN www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 22 D-F20 IC601 CXD3037R ERROR CORRECTOR 32K RAM EFM DEMODULATOR SUB CODE PROCESSOR SERVO AUTO SEQUENCER D/A INTERFACE VIBRATION MEMORY CONTROLLER + COMPRESSION EXPANDER DAC SELECTOR DIGITAL OUT ASYMMETRY CORRECTOR DIGITAL PLL DIGITAL CLV CPU INTERFACE OP AMP ANALOG SWITCH SERVO BLOCK SIGNAL PROCESSOR BLOCK MEMORY CONTROLLER, BUS BOOST BLOCK A/D CONVERTER SERVO INTERFACE SERVO DSP FOCUS SERVO SLED SERVO TRACKING SERVO CLOCK GENERATOR LPF LPF MIRR DFCT FOK PWM GENERATOR FOCUS PWM GENERATOR SLED PWM GENERATOR TRACKING PWM GENERATOR 90 89 88 87 86 85 84 83 82 81 80 79 78 77 76 75 74 73 72 71 70 69 68 67 66 65 64 63 62 61 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60 XOE A0 – A11 SYSM AMUTE HPL/HP HPM HPR PCMDI LRCKI BCKI AOUT1 AIN1 LOUT1 LOUT2 AIN2 AOUT2 A9 A8 A7 DVSS RFAC XTAO XTAI XTSL VCTL VPCO WFCK GFS XUGF MDS C2PO WDCK BIAS ASYI ASYO FILO FILI PCO PWMI MDP SDTI SCSY SCOR SBSO EXCK SDTO XLAT CLOK SENS XSOE R4M IGEN VDD0 COUT MIRR DFCT FOK PWMI/HPVSS LOCK/HPL HPR HPM HPL/HPVDD(2.5V) VDD1(2.0V) C176 MDP MDS SSTP SFDR SRDR TFDR TRDR FFDR FRDR FRDR FFDR TRDR TFDR SRDR SFDR SCLK ATSK SSTP COUT FOK DFCT MIRR VSS1 TEST TES1 AVDD0(2.5V) IGEN AVSS0 RFDC E F 120 119 118 117 116 115 114 113 112 111 110 109 108 107 106 105 104 103 102 101 100 99 98 97 96 95 94 93 92 91 XOE XCAS D2 D3 D0 D1 XWE XRAS A11 A10 DVDD(2.5V) A0 A1 A2 A3 AVDD2(2.5V) ROUT AIN2 AOUT2 AVSS2 AVSS1 AOUT1 AIN1 LOUT AVDD1(2.5V) XVSS XTAO XTAI XVDD BCKI XOE XCAS D2 D3 D0 D1 XWE XRAS A11 A10 DVDD A0 A1 A2 A3 AVDD2 LOUT2 AIN2 AOUT2 AVSS2 AVSS1 AOUT1 AIN1 LOUT1 AVDD1 XVSS XTAO XTAI XVDD BCKI VDD0 COUT MIRR DFCT FOK PWMI HPR HPM HPL/HP VDD1 MDP MDS SSTP SFDR SRDR TFDR TRDR FFDR FRDR VSS1 A VDD A GND D VDD AVDD0 IGEN AVSS0 RFDC E F RFDC E F B A VC CLTV XPCK A6 A5 A4 XWRE XRDE XEMP XWIH XQOK AMUTE SDTI XQCK SCSY SCOR VSS0 SBSO EXCK XRST SYSM SDTO XLAT CLOK SENS SCLK XSOE ATSK R4M A9 A8 A7 DVSS A6 A5 A4 XWRE XRDE XEMP XWIH XQOK AMUTE SDTI SCSY SCOR VSS0 D GND SBSO EXCK SYSM SDTO XLAT CLOK SENS SCLK XSOE ATSK R4M BCK PCMDI PCMD LRCKI LRCK DOUT VDD2(2.0V) WFCK C2PO GFS XPCK XUGF WDCK VSS2 XTSL AVDD3(2.0V) ASYO ASYI BIAS RFAC AVSS3 CLTV PCO FILI FILO VCTL VPCO VC A B BCK PCMDI PCMD LRCKI LRCK DOUT VDD2 WFCK C2PO GFS XPCK XUGF WDCK VSS2 XTSL AVDD3 ASYO ASYI BIAS RFAC AVSS3 CLTV PCO FILI FILO VCTL VPCO VC A B XCAS D0 – D4 XWE BCK PCMD LRCK DOUT XWRE XRAS XRDE XQOK XWIH XEMP www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 23 D-F20 IC401 TB2125F VLGO1 48 INP1 47 RF1 46 INM1 DTC1D VCC1(2.5V) VCPU1(2.5V) DCIN RF4 INM4 RS CHGSW RI2 FI2 34 RI1 33 32 FI1 L4 VG GND 5 SYNC 4 RSTB 6 CLOCK 7 8 DATA WAKEUP 9 LATCH FO1 31 MGND1 30 RO1 29 VD12 28 FO2 27 MGND2 26 RO2 24 VD23A 23 FO3 22 MGND3 21 RO3 20 VD34 19 FO4 18 MGND4 17 RO4 L1L PGND1 L1H VIN STNG BATM1 VREF BATM2 CHGMNT RF21 PAPC VINDET RF2 APCREF INM2 49 50 51 52 53 54 55 56 57 58 59 60 62 63 61 64 1 2 3 LEVEL SHIFTER H BRIDGE DRIVER 4 H BRIDGE DRIVER 3 H BRIDGE DRIVER 2 H BRIDGE DRIVER 1 CONTROLLER STANDBY REFERENCE BANDGAP REFERENCE (VREF) CLK OR OSC SAW GEN 25 VD23B 45 44 43 41 40 39 38 37 36 CONTROL CHARGE VREF VREF VREF DCIN COMP OUT MDP SAW TOOTH 10 11 12 VG VCPU 1/2 VREF SAW TOOTH SAW TOOTH VREF VREF VCPU CLK VCPU VCPU VCPU VCPU VCPU VG VCPU VCPU VCPU VCPU VCPU2 VCPU SUB VREF SUB VREF VCC1 VG VCPU DCIN DCIN VG VCPU2 VCPU VCPU VIN VCPU DCIN VG VG VG VG VIN VCPU2 VCPU VCPU2(2.0V) 42 DCIN OEB BIAS INTERFACE CLK R-2 R-1 R-6 D-1 to 4 S-3 S-1 D-5 S-2 R-5 CHGON/OFF 35 13 FI3 14 RI3 15 PWM/FI4 16 PDL/RI4 VCPU2 R-4 VREF VIN VREF VCPU VCPU VCPU www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 24 D-F20 SECTION 6 EXPLODED VIEWS Ref. No. Part No. Description Remark 6-1. CABINET (FRONT) SECTION Ref. No. Part No. Description Remark 1 X-3380-752-1 LID ASSY, UPPER 2 3-336-395-01 SCREW (B2X10) (G), TAPPING 3 X-3380-754-1 CABINET (FRONT) ASSY NOTE: • The mechanical parts with no reference number in the exploded views are not supplied. • Items marked “*” are not stocked since they are seldom required for routine service. Some delay should be anticipated when ordering these items. • Color Indication of Appearance Parts Example : KNOB, BALANCE (WHITE) ... (RED) Parts Color Cabinet’s Color • Accessories and packing materials are given in the last of this parts list. R R 4 3-231-897-01 BUTTON (OPEN) 5 3-232-612-01 KNOB (JOGGABLE) 6 3-231-037-01 LID, BATTERY CASE 1 2 5 3 4 6 2 The components identified by mark 0 or dotted line with mark 0 are critical for safety. Replace only with part number specified. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 25 D-F20 6-2. CABINET (LOWER) SECTION Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 51 4-222-765-11 INSULATOR * 52 A-3021-498-A MAIN BOARD, COMPLETE 53 3-231-036-01 HOLDER, LCD 54 3-231-411-01 TERMINAL (–), BATTERY (BT402) 55 3-222-860-01 TERMINAL (+.–), BATTERY (BT400) 56 4-218-592-01 CUSHION 57 3-231-676-01 TERMINAL (LINK 4), BATTERY (BT401) 58 3-222-862-01 SPRING (TORSION) 59 X-3380-753-1 CABINET (LOWER) SUB ASSY 60 3-222-857-01 KNOB (HOLD) 61 4-974-607-11 FOOT, RUBBER * 62 3-232-351-01 PAPER, SHIELD 63 3-234-025-01 SHEET, INSULATING 64 3-234-026-01 PAPER (CABINET), SHIELD LCD1 1-804-462-11 DISPLAY PANEL, LIQUID CRYSTAL 51 51 56 51 52 53 57 58 55 54 62 63 59 64 60 61 CDM-3123EBA LCD1 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 26 D-F20 6-3. CD MECHANISM DECK SECTION (CDM-3123EBA) Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 101 102 103 104 105 106 107 108 109 110 M501 M502 111 112 109 The components identified by mark 0 or dotted line with mark 0 are critical for safety. Replace only with part number specified. 101 4-218-820-01 CHASSIS 102 4-218-827-01 RETAINER, SHAFT 103 3-686-458-03 SCREW (P1.4X3.5), TAPPING 104 A-3328-628-A SCREW (FEED) ASSY 105 4-220-645-01 SHAFT, STANDARD 106 4-223-600-01 RACK 107 3-895-823-61 SCREW (B1.4X2.3), TAPPING 0108 X-4952-506-1 PICK-UP BLOCK, OPTICAL (DAX-23E) 109 3-318-203-71 SCREW (B1.7X5), TAPPING 110 4-218-821-01 COVER, GEAR 111 4-218-823-01 GEAR (B) 112 4-218-825-01 SPRING, SLED M501 A-3328-627-A MOTOR ASSY, SLED (SLED) M502 A-3328-759-A MOTOR ASSY, TURNTABLE (SPINDLE) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 27 D-F20 SECTION 7 ELECTRICAL PARTS LIST Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark MAIN NOTE: • Due to standardization, replacements in the parts list may be different from the parts specified in the diagrams or the components used on the set. • RESISTORS All resistors are in ohms. METAL:Metal-film resistor. METAL OXIDE: Metal oxide-film resistor. F:nonflammable • Items marked “*” are not stocked since they are seldom required for routine service. Some delay should be anticipated when ordering these items. • SEMICONDUCTORS In each case, u : µ, for example: uA.. : µA.. uPA.. : µPA.. uPB.. : µPB.. uPC.. : µPC.. uPD.. : µPD.. • CAPACITORS uF : µF • COILS uH : µH * A-3021-498-A MAIN BOARD, COMPLETE ********************* 3-222-860-01 TERMINAL (+.–), BATTERY (BT400) 3-231-036-01 HOLDER, LCD 3-231-411-01 TERMINAL (–), BATTERY (BT402) * 3-232-351-01 PAPER, SHIELD 3-234-025-01 SHEET, INSULATING < CAPACITOR > C2 1-162-917-11 CERAMIC CHIP 15PF 5% 50V C4 1-162-917-11 CERAMIC CHIP 15PF 5% 50V C5 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V C9 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C10 1-162-959-11 CERAMIC CHIP 330PF 5% 50V C12 1-162-927-11 CERAMIC CHIP 100PF 5% 50V C13 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V C15 1-162-923-11 CERAMIC CHIP 47PF 5% 50V C16 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C17 1-115-156-11 CERAMIC CHIP 1uF 10V C18 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C19 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C20 1-109-982-11 CERAMIC CHIP 1uF 10% 10V C21 1-164-156-11 CERAMIC CHIP 0.1uF 25V C23 1-162-962-11 CERAMIC CHIP 470PF 10% 50V C24 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C25 1-124-635-00 ELECT 220uF 20% 6.3V C26 1-125-837-11 CERAMIC CHIP 1uF 10% 6.3V C27 1-117-720-11 CERAMIC CHIP 4.7uF 10V C28 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V C29 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V C33 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C34 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C35 1-104-852-11 TANTAL. CHIP 22uF 20% 10V C36 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C38 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C39 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C40 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C42 1-216-864-11 METAL CHIP 0 5% 1/16W C43 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V C44 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V C45 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C46 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C47 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C50 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V C51 1-164-156-11 CERAMIC CHIP 0.1uF 25V C52 1-164-156-11 CERAMIC CHIP 0.1uF 25V C54 1-115-156-11 CERAMIC CHIP 1uF 10V C57 1-126-154-11 ELECT 47uF 20% 6.3V C58 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C59 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C60 1-162-927-11 CERAMIC CHIP 100PF 5% 50V C61 1-162-927-11 CERAMIC CHIP 100PF 5% 50V C62 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V C63 1-162-919-11 CERAMIC CHIP 22PF 5% 50V C64 1-162-917-11 CERAMIC CHIP 15PF 5% 50V C65 1-113-619-11 CERAMIC CHIP 0.47uF 10V C66 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C67 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C68 1-113-619-11 CERAMIC CHIP 0.47uF 10V C69 1-124-584-00 ELECT 100uF 20% 10V C71 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C76 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C81 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V C82 1-164-489-11 CERAMIC CHIP 0.22uF 10% 16V C83 1-162-927-11 CERAMIC CHIP 100PF 5% 50V C85 1-164-505-11 CERAMIC CHIP 2.2uF 16V C86 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V C87 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V C88 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C89 1-164-505-11 CERAMIC CHIP 2.2uF 16V C90 1-104-852-11 TANTAL. CHIP 22uF 20% 10V C92 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C93 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C94 1-164-156-11 CERAMIC CHIP 0.1uF 25V C95 1-126-153-11 ELECT 22uF 20% 6.3V C97 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C101 1-125-838-11 CERAMIC CHIP 2.2uF 10% 6.3V C102 1-164-217-11 CERAMIC CHIP 150PF 5% 50V C103 1-162-963-11 CERAMIC CHIP 680PF 10% 50V C104 1-162-962-11 CERAMIC CHIP 470PF 10% 50V C154 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C201 1-125-838-11 CERAMIC CHIP 2.2uF 10% 6.3V C202 1-164-217-11 CERAMIC CHIP 150PF 5% 50V C203 1-162-963-11 CERAMIC CHIP 680PF 10% 50V C204 1-162-962-11 CERAMIC CHIP 470PF 10% 50V C254 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C300 1-125-838-11 CERAMIC CHIP 2.2uF 10% 6.3V C313 1-104-852-11 TANTAL. CHIP 22uF 20% 10V C318 1-164-156-11 CERAMIC CHIP 0.1uF 25V The components identified by mark 0 or dotted line with mark 0 are critical for safety. Replace only with part number specified. When indicating parts by reference number, please include the board. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 28 D-F20 Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark MAIN C319 1-164-156-11 CERAMIC CHIP 0.1uF 25V C350 1-115-156-11 CERAMIC CHIP 1uF 10V C351 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C352 1-135-854-21 ELECT CHIP 10uF 20% 16V C353 1-135-854-21 ELECT CHIP 10uF 20% 16V C354 1-137-934-11 TANTAL. CHIP 47uF 20% 10V C359 1-109-982-11 CERAMIC CHIP 1uF 10% 10V C360 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C401 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C402 1-164-505-11 CERAMIC CHIP 2.2uF 16V C403 1-162-927-11 CERAMIC CHIP 100PF 5% 50V C404 1-104-913-11 TANTAL. CHIP 10uF 20% 16V C405 1-115-156-11 CERAMIC CHIP 1uF 10V C406 1-128-057-11 ELECT 330uF 20% 6.3V C407 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C408 1-162-919-11 CERAMIC CHIP 22PF 5% 50V C409 1-124-584-00 ELECT 100uF 20% 10V C410 1-124-584-00 ELECT 100uF 20% 10V C411 1-801-862-11 VARISTOR (CHIP TYPE) C412 1-164-156-11 CERAMIC CHIP 0.1uF 25V C413 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C414 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V C415 1-164-156-11 CERAMIC CHIP 0.1uF 25V C416 1-164-156-11 CERAMIC CHIP 0.1uF 25V C417 1-110-569-11 TANTAL. CHIP 47uF 20% 6.3V C418 1-124-584-00 ELECT 100uF 20% 10V C419 1-127-760-11 CERAMIC CHIP 4.7uF 10% 6.3V C420 1-109-982-11 CERAMIC CHIP 1uF 10% 10V C421 1-127-760-11 CERAMIC CHIP 4.7uF 10% 6.3V C422 1-162-959-11 CERAMIC CHIP 330PF 5% 50V C423 1-109-982-11 CERAMIC CHIP 1uF 10% 10V C424 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V C427 1-110-569-11 TANTAL. CHIP 47uF 20% 4V C428 1-124-233-11 ELECT 10uF 20% 16V C430 1-164-156-11 CERAMIC CHIP 0.1uF 25V C432 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C436 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C437 1-115-156-11 CERAMIC CHIP 1uF 10V C450 1-115-156-11 CERAMIC CHIP 1uF 10V C451 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C452 1-115-156-11 CERAMIC CHIP 1uF 10V C453 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V C461 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V C462 1-162-925-11 CERAMIC CHIP 68PF 5% 50V C500 1-109-982-11 CERAMIC CHIP 1uF 10% 10V C502 1-126-153-11 ELECT 22uF 20% 6.3V C601 1-162-927-11 CERAMIC CHIP 100PF 5% 50V C602 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V C603 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C604 1-162-965-11 CERAMIC CHIP 0.0015uF 10% 50V C605 1-164-156-11 CERAMIC CHIP 0.1uF 25V C606 1-162-927-11 CERAMIC CHIP 100PF 5% 50V C607 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V C609 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V C611 1-162-917-11 CERAMIC CHIP 15PF 5% 50V C612 1-162-962-11 CERAMIC CHIP 470PF 10% 50V C613 1-162-962-11 CERAMIC CHIP 470PF 10% 50V C614 1-162-962-11 CERAMIC CHIP 470PF 10% 50V C615 1-162-962-11 CERAMIC CHIP 470PF 10% 50V C618 1-125-837-11 CERAMIC CHIP 1uF 10% 6.3V C619 1-162-927-11 CERAMIC CHIP 100PF 5% 50V C620 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V C621 1-164-230-11 CERAMIC CHIP 220PF 5% 50V C622 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V C623 1-115-156-11 CERAMIC CHIP 1uF 10V C624 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C625 1-104-847-11 TANTAL. CHIP 22uF 20% 4V C626 1-104-847-11 TANTAL. CHIP 22uF 20% 4V C627 1-164-156-11 CERAMIC CHIP 0.1uF 25V C628 1-801-862-11 VARISTOR (CHIP TYPE) C629 1-164-505-11 CERAMIC CHIP 2.2uF 16V C631 1-162-923-11 CERAMIC CHIP 47PF 5% 50V C632 1-164-156-11 CERAMIC CHIP 0.1uF 25V C634 1-124-635-00 ELECT 220uF 20% 6.3V C635 1-115-156-11 CERAMIC CHIP 1uF 10V C636 1-164-156-11 CERAMIC CHIP 0.1uF 25V C637 1-104-847-11 TANTAL. CHIP 22uF 20% 4V C640 1-109-982-11 CERAMIC CHIP 1uF 10% 10V C804 1-109-982-11 CERAMIC CHIP 1uF 10% 10V C805 1-164-156-11 CERAMIC CHIP 0.1uF 25V C807 1-164-156-11 CERAMIC CHIP 0.1uF 25V C810 1-164-156-11 CERAMIC CHIP 0.1uF 25V C811 1-117-720-11 CERAMIC CHIP 4.7uF 10V C813 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V C841 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V < FILTER > CF1 1-781-271-11 FILTER, CERAMIC (450kHz) CF3 1-795-035-11 FILTER, CERAMIC (10.7MHz) < CONNECTOR > * CN501 1-815-223-21 CONNECTOR, FFC/FPC (ZIF) 13P CN502 1-784-342-11 HOUSING, CONNECTOR 2P CN503 1-784-342-21 HOUSING, CONNECTOR 2P < TRIMMER > CT1 1-141-646-11 CAP, TRIMMER 10PF CT3 1-141-646-11 CAP, TRIMMER 10PF < DIODE > D1 8-719-080-77 DIODE MA2S357(E)-(TX).SO D2 8-719-080-77 DIODE MA2S357(E)-(TX).SO D3 8-719-076-70 DIODE KV1520TL D80 8-719-404-50 DIODE MA111-TX D82 8-719-420-87 DIODE MA8130 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 29 D-F20 Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark MAIN D301 8-719-404-50 DIODE MA111-TX D302 8-719-404-50 DIODE MA111-TX D303 8-719-404-50 DIODE MA111-TX D304 8-719-404-50 DIODE MA111-TX D401 8-719-081-83 DIODE CRG01(TE85L) D402 8-719-404-50 DIODE MA111-TX D404 8-719-081-83 DIODE CRG01(TE85L) D405 8-719-072-70 DIODE MA2ZD14001S0 D406 8-719-058-24 DIODE RB501V-40TE-17 D407 8-719-421-27 DIODE MA728 D408 8-719-072-70 DIODE MA2ZD14001S0 D409 8-719-404-50 DIODE MA111-TX D415 8-719-976-96 DIODE DTZ4.7C D461 8-719-072-70 DIODE MA2ZD14001S0 D601 8-719-044-74 DIODE MA792WK-TX D602 8-719-071-87 DIODE MA785-(TX).SO D801 8-719-404-50 DIODE MA111-TX < FERRITE BEAD > FB11 1-216-864-11 METAL CHIP 0 5% 1/16W FB12 1-216-864-11 METAL CHIP 0 5% 1/16W FB111 1-414-813-11 FERRITE, EMI (SMD) FB211 1-414-813-11 FERRITE, EMI (SMD) FB311 1-414-813-11 FERRITE, EMI (SMD) FB602 1-216-803-11 METAL CHIP 33 5% 1/16W FB603 1-469-570-21 INDUCTOR, CHIP 10uH < BPF > FL1 1-236-711-21 FILTER, BAND PASS < IC > IC1 6-700-436-01 IC TA2149BFN IC61 6-800-309-01 IC TC9327AF-631 IC62 8-759-449-23 IC AK93C55AV-L IC81 8-759-457-70 IC XC62RP1602MR IC302 8-759-681-65 IC TA2120FN(EL) IC303 8-759-523-03 IC TC74HC4066AFT(EL) IC401 8-759-714-74 IC TB2125F IC601 8-752-401-56 IC CXD3037R IC801 6-800-307-01 IC TMP88CM22AF-Z3TU01 < JACK > J302 1-565-287-41 JACK (i) J401 1-778-153-21 JACK, DC (POLARITY UNIFIED TYPE) (DC IN 4.5V) < JUMPER RESISTOR > JC1 1-216-864-11 METAL CHIP 0 5% 1/16W < COIL > L1 1-416-036-11 COIL, AIR-CORE L2 1-416-623-11 COIL (WITH CORE) L3 1-424-851-11 ANTENNA, FERRITE-ROD (AM) L4 1-424-883-11 COIL (AM OSC) L5 1-469-570-21 INDUCTOR 10uH L6 1-216-295-11 SHORT 0 L61 1-216-817-11 METAL CHIP 470 5% 1/16W L62 1-469-570-21 INDUCTOR 10uH L80 1-469-570-21 INDUCTOR 10uH L312 1-410-389-31 INDUCTOR 47uH L401 1-419-387-11 INDUCTOR 100uH L402 1-414-398-11 INDUCTOR 10uH L408 1-410-389-31 INDUCTOR 47uH L409 1-410-389-31 INDUCTOR 47uH L410 1-410-389-31 INDUCTOR 47uH L412 1-412-054-21 INDUCTOR 2.2uH L413 1-410-389-31 INDUCTOR 47uH L601 1-412-987-31 INDUCTOR 4.7uH < LIQUID CRYSTAL DISPLAY > LCD1 1-804-462-11 DISPLAY PANEL, LIQUID CRYSTAL < TRANSISTOR > Q2 8-729-028-97 TRANSISTOR DTC114TUA-T106 Q3 8-729-423-52 TRANSISTOR 2SC3931-C Q4 8-729-800-71 TRANSISTOR 2SB815B7-TB Q5 8-729-028-97 TRANSISTOR DTC114TUA-T106 Q6 8-729-028-97 TRANSISTOR DTC114TUA-T106 Q60 8-729-423-52 TRANSISTOR 2SC3931-C Q61 8-729-028-97 TRANSISTOR DTC114TUA-T106 Q84 8-729-230-63 TRANSISTOR 2SC4116-YG Q85 8-729-053-44 FET 2SK880-Y-TE85R Q86 8-729-602-21 TRANSISTOR 2SC4154-F Q401 8-729-807-34 TRANSISTOR 2SB1123-S Q402 8-729-028-97 TRANSISTOR DTC114TUA-T106 Q403 8-729-026-53 TRANSISTOR 2SA1576A-T106-QR Q405 8-729-905-34 TRANSISTOR 2SC4081-Q Q406 8-729-026-53 TRANSISTOR 2SA1576A-T106-QR Q407 8-729-427-74 TRANSISTOR XP4601 Q408 8-729-029-10 TRANSISTOR DTC143TUA-T106 Q409 8-729-905-34 TRANSISTOR 2SC4081-Q Q410 8-729-922-10 TRANSISTOR 2SA1577-QR Q411 8-729-905-34 TRANSISTOR 2SC4081-Q Q412 8-729-026-53 TRANSISTOR 2SA1576A-T106-QR Q413 8-729-047-36 FET CPH3303-TL < RESISTOR > R1 1-216-849-11 METAL CHIP 220K 5% 1/16W R2 1-216-825-11 METAL CHIP 2.2K 5% 1/16W R3 1-216-835-11 METAL CHIP 15K 5% 1/16W R4 1-216-845-11 METAL CHIP 100K 5% 1/16W R5 1-216-833-11 METAL CHIP 10K 5% 1/16W R7 1-216-849-11 METAL CHIP 220K 5% 1/16W R9 1-216-813-11 METAL CHIP 220 5% 1/16W www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 30 D-F20 Ref. No. Part No. Description Remark MAIN R10 1-216-821-11 METAL CHIP 1K 5% 1/16W R12 1-216-827-11 METAL CHIP 3.3K 5% 1/16W R13 1-216-817-11 METAL CHIP 470 5% 1/16W R15 1-216-789-11 METAL CHIP 2.2 5% 1/16W R16 1-216-829-11 METAL CHIP 4.7K 5% 1/16W R17 1-216-829-11 METAL CHIP 4.7K 5% 1/16W R18 1-216-849-11 METAL CHIP 220K 5% 1/16W R19 1-216-837-11 METAL CHIP 22K 5% 1/16W R25 1-216-864-11 METAL CHIP 0 5% 1/16W R26 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V R41 1-216-817-11 METAL CHIP 470 5% 1/16W R42 1-216-864-11 METAL CHIP 0 5% 1/16W R46 1-216-833-11 METAL CHIP 10K 5% 1/16W R47 1-216-833-11 METAL CHIP 10K 5% 1/16W R48 1-216-845-11 METAL CHIP 100K 5% 1/16W R49 1-216-845-11 METAL CHIP 100K 5% 1/16W R50 1-216-817-11 METAL CHIP 470 5% 1/16W R51 1-216-817-11 METAL CHIP 470 5% 1/16W R52 1-216-841-11 METAL CHIP 47K 5% 1/16W R53 1-216-841-11 METAL CHIP 47K 5% 1/16W R54 1-216-845-11 METAL CHIP 100K 5% 1/16W R55 1-216-845-11 METAL CHIP 100K 5% 1/16W R56 1-216-845-11 METAL CHIP 100K 5% 1/16W R60 1-216-841-11 METAL CHIP 47K 5% 1/16W R61 1-216-797-11 METAL CHIP 10 5% 1/16W R62 1-216-825-11 METAL CHIP 2.2K 5% 1/16W R63 1-216-845-11 METAL CHIP 100K 5% 1/16W R64 1-216-829-11 METAL CHIP 4.7K 5% 1/16W R80 1-216-833-11 METAL CHIP 10K 5% 1/16W R81 1-216-864-11 METAL CHIP 0 5% 1/16W R82 1-216-835-11 METAL CHIP 15K 5% 1/16W R84 1-216-827-11 METAL CHIP 3.3K 5% 1/16W R85 1-216-843-11 METAL CHIP 68K 5% 1/16W R86 1-216-813-11 METAL CHIP 220 5% 1/16W R87 1-216-845-11 METAL CHIP 100K 5% 1/16W R88 1-216-821-11 METAL CHIP 1K 5% 1/16W R89 1-216-295-11 SHORT 0 R91 1-216-845-11 METAL CHIP 100K 5% 1/16W R102 1-216-829-11 METAL CHIP 4.7K 5% 1/16W R103 1-216-833-11 METAL CHIP 10K 5% 1/16W R104 1-216-833-11 METAL CHIP 10K 5% 1/16W R107 1-216-833-11 METAL CHIP 10K 5% 1/16W R109 1-216-843-11 METAL CHIP 68K 5% 1/16W R110 1-216-864-11 METAL CHIP 0 5% 1/16W R154 1-216-793-11 RES-CHIP 4.7 5% 1/16W R202 1-216-829-11 METAL CHIP 4.7K 5% 1/16W R203 1-216-833-11 METAL CHIP 10K 5% 1/16W R204 1-216-833-11 METAL CHIP 10K 5% 1/16W R207 1-216-833-11 METAL CHIP 10K 5% 1/16W R209 1-216-843-11 METAL CHIP 68K 5% 1/16W R210 1-216-864-11 METAL CHIP 0 5% 1/16W R254 1-216-793-11 RES-CHIP 4.7 5% 1/16W R305 1-216-845-11 METAL CHIP 100K 5% 1/16W R308 1-216-845-11 METAL CHIP 100K 5% 1/16W R317 1-216-857-11 METAL CHIP 1M 5% 1/16W R353 1-216-295-11 SHORT 0 R401 1-216-857-11 METAL CHIP 1M 5% 1/16W R402 1-216-839-11 METAL CHIP 33K 5% 1/16W R403 1-216-853-11 METAL CHIP 470K 5% 1/16W R404 1-216-839-11 METAL CHIP 33K 5% 1/16W R405 1-216-789-11 METAL CHIP 2.2 5% 1/16W R406 1-216-837-11 METAL CHIP 22K 5% 1/16W R407 1-216-295-11 SHORT 0 R408 1-216-857-11 METAL CHIP 1M 5% 1/16W R409 1-216-849-11 METAL CHIP 220K 5% 1/16W R410 1-216-843-11 METAL CHIP 68K 5% 1/16W R412 1-216-845-11 METAL CHIP 100K 5% 1/16W R415 1-216-833-11 METAL CHIP 10K 5% 1/16W R416 1-216-857-11 METAL CHIP 1M 5% 1/16W R417 1-216-811-11 METAL CHIP 150 5% 1/16W R418 1-218-891-11 METAL CHIP 68K 0.5% 1/16W R419 1-218-903-11 METAL CHIP 220K 0.5% 1/16W R421 1-216-833-11 METAL CHIP 10K 5% 1/16W R422 1-216-821-11 METAL CHIP 1K 5% 1/16W R423 1-216-841-11 METAL CHIP 47K 5% 1/16W R424 1-216-839-11 METAL CHIP 33K 5% 1/16W R425 1-216-821-11 METAL CHIP 1K 5% 1/16W R429 1-216-821-11 METAL CHIP 1K 5% 1/16W R430 1-216-833-11 METAL CHIP 10K 5% 1/16W R431 1-216-829-11 METAL CHIP 4.7K 5% 1/16W R432 1-216-295-11 SHORT 0 R440 1-216-825-11 METAL CHIP 2.2K 5% 1/16W R442 1-218-883-11 METAL CHIP 33K 0.5% 1/16W R449 1-216-845-11 METAL CHIP 100K 5% 1/16W R450 1-216-819-11 METAL CHIP 680 5% 1/16W R451 1-218-903-11 METAL CHIP 220K 0.5% 1/16W R452 1-218-887-11 METAL CHIP 47K 0.5% 1/16W R453 1-218-887-11 METAL CHIP 47K 0.5% 1/16W R454 1-218-887-11 METAL CHIP 47K 0.5% 1/16W R455 1-216-839-11 METAL CHIP 33K 5% 1/16W R458 1-216-833-11 METAL CHIP 10K 5% 1/16W R459 1-216-864-11 METAL CHIP 0 5% 1/16W R460 1-216-864-11 METAL CHIP 0 5% 1/16W R461 1-216-845-11 METAL CHIP 100K 5% 1/16W R462 1-216-841-11 METAL CHIP 47K 5% 1/16W R463 1-216-857-11 METAL CHIP 1M 5% 1/16W R464 1-216-853-11 METAL CHIP 470K 5% 1/16W R466 1-216-841-11 METAL CHIP 47K 5% 1/16W R467 1-216-864-11 METAL CHIP 0 5% 1/16W R468 1-216-843-11 METAL CHIP 68K 5% 1/16W R469 1-216-845-11 METAL CHIP 100K 5% 1/16W R470 1-216-853-11 METAL CHIP 470K 5% 1/16W R481 1-414-813-21 FERRITE, EMI (SMD) R482 1-216-295-11 SHORT 0 R483 1-216-295-11 SHORT 0 R484 1-216-295-11 SHORT 0 Ref. No. Part No. Description Remark www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 31 D-F20 R485 1-216-295-11 SHORT 0 R486 1-216-864-11 METAL CHIP 0 5% 1/16W R500 1-216-864-11 METAL CHIP 0 5% 1/16W R603 1-216-851-11 METAL CHIP 330K 5% 1/16W R604 1-216-857-11 METAL CHIP 1M 5% 1/16W R605 1-216-827-11 METAL CHIP 3.3K 5% 1/16W R606 1-216-827-11 METAL CHIP 3.3K 5% 1/16W R607 1-216-833-11 METAL CHIP 10K 5% 1/16W R608 1-216-853-11 METAL CHIP 470K 5% 1/16W R609 1-216-833-11 METAL CHIP 10K 5% 1/16W R610 1-216-864-11 METAL CHIP 0 5% 1/16W R611 1-216-837-11 METAL CHIP 22K 5% 1/16W R612 1-216-841-11 METAL CHIP 47K 5% 1/16W R613 1-216-837-11 METAL CHIP 22K 5% 1/16W R614 1-216-843-11 METAL CHIP 68K 5% 1/16W R615 1-216-837-11 METAL CHIP 22K 5% 1/16W R616 1-216-843-11 METAL CHIP 68K 5% 1/16W R617 1-216-837-11 METAL CHIP 22K 5% 1/16W R618 1-216-847-11 METAL CHIP 150K 5% 1/16W R619 1-216-837-11 METAL CHIP 22K 5% 1/16W R620 1-216-847-11 METAL CHIP 150K 5% 1/16W R621 1-216-864-11 METAL CHIP 0 5% 1/16W R623 1-216-819-11 METAL CHIP 680 5% 1/16W R624 1-216-845-11 METAL CHIP 100K 5% 1/16W R625 1-216-833-11 METAL CHIP 10K 5% 1/16W R626 1-216-817-11 METAL CHIP 470 5% 1/16W R627 1-216-817-11 METAL CHIP 470 5% 1/16W R628 1-216-817-11 METAL CHIP 470 5% 1/16W R629 1-216-833-11 METAL CHIP 10K 5% 1/16W R630 1-216-864-11 METAL CHIP 0 5% 1/16W R632 1-216-839-11 METAL CHIP 33K 5% 1/16W R634 1-216-807-11 METAL CHIP 68 5% 1/16W R636 1-216-864-11 METAL CHIP 0 5% 1/16W R637 1-216-839-11 METAL CHIP 33K 5% 1/16W R638 1-216-864-11 METAL CHIP 0 5% 1/16W R639 1-216-819-11 METAL CHIP 680 5% 1/16W R640 1-216-819-11 METAL CHIP 680 5% 1/16W R641 1-216-864-11 METAL CHIP 0 5% 1/16W R642 1-216-864-11 METAL CHIP 0 5% 1/16W R643 1-216-819-11 METAL CHIP 680 5% 1/16W R645 1-216-864-11 METAL CHIP 0 5% 1/16W R646 1-216-849-11 METAL CHIP 220K 5% 1/16W R650 1-414-760-21 FERRITE, EMI (SMD) R651 1-216-809-11 METAL CHIP 100 5% 1/16W R801 1-216-845-11 METAL CHIP 100K 5% 1/16W R802 1-216-819-11 METAL CHIP 680 5% 1/16W R803 1-216-819-11 METAL CHIP 680 5% 1/16W R804 1-216-819-11 METAL CHIP 680 5% 1/16W R805 1-216-821-11 METAL CHIP 1K 5% 1/16W R806 1-216-821-11 METAL CHIP 1K 5% 1/16W R810 1-216-845-11 METAL CHIP 100K 5% 1/16W R811 1-216-864-11 METAL CHIP 0 5% 1/16W R813 1-216-845-11 METAL CHIP 100K 5% 1/16W Ref. No. Part No. Description Remark R814 1-216-833-11 METAL CHIP 10K 5% 1/16W R816 1-216-829-11 METAL CHIP 4.7K 5% 1/16W R820 1-216-833-11 METAL CHIP 10K 5% 1/16W R822 1-216-829-11 METAL CHIP 4.7K 5% 1/16W R824 1-216-845-11 METAL CHIP 100K 5% 1/16W R829 1-216-845-11 METAL CHIP 100K 5% 1/16W R830 1-216-845-11 METAL CHIP 100K 5% 1/16W R831 1-216-845-11 METAL CHIP 100K 5% 1/16W R841 1-216-857-11 METAL CHIP 1M 5% 1/16W R842 1-216-864-11 METAL CHIP 0 5% 1/16W R845 1-216-845-11 METAL CHIP 100K 5% 1/16W R850 1-218-871-11 METAL CHIP 10K 0.5% 1/16W R851 1-216-821-11 METAL CHIP 1K 5% 1/16W R852 1-216-823-11 METAL CHIP 1.5K 5% 1/16W R853 1-216-827-11 METAL CHIP 3.3K 5% 1/16W R854 1-216-829-11 METAL CHIP 4.7K 5% 1/16W R855 1-216-837-11 METAL CHIP 22K 5% 1/16W R856 1-216-841-11 METAL CHIP 47K 5% 1/16W R857 1-216-825-11 METAL CHIP 2.2K 5% 1/16W R858 1-216-833-11 METAL CHIP 10K 5% 1/16W R859 1-216-831-11 METAL CHIP 6.8K 5% 1/16W R860 1-216-864-11 METAL CHIP 0 5% 1/16W < VARIABLE RESISTOR > RV301 1-225-953-11 RES, VAR, CARBON 10KX2 (VOLUME) < SWITCH > S801 1-692-440-11 SWITCH, PUSH (CD DOOR OPEN) S802 1-553-977-00 SWITCH, SLIDE (AVLS) S803 1-762-078-11 SWITCH, SLIDE (HOLD) S804 1-553-977-00 SWITCH, SLIDE (ESP) S805 1-692-014-11 SWITCH, KEYBOARD (N X) S806 1-692-014-11 SWITCH, KEYBOARD (RADIO ON• BAND/MEMORY) S807 1-692-014-11 SWITCH, KEYBOARD (x•RADIO OFF) S808 1-692-014-11 SWITCH, KEYBOARD (>,TUNE +) S809 1-692-014-11 SWITCH, KEYBOARD (.,TUNE –) S810 1-692-014-11 SWITCH, KEYBOARD (MENU/PRESET +) S811 1-692-014-11 SWITCH, KEYBOARD (SOUND/PRESET –) S812 1-762-078-11 SWITCH, SLIDE (STEP) S813 1-762-078-11 SWITCH, SLIDE (LOCAL/DX) < TRANSFORMER > T1 1-416-594-11 TRANSFORMER, IF T81 1-449-021-21 TRANSFORMER, DC/DC CONVERTER < VARISTOR > VDR101 1-801-862-11 VARISTOR (CHIP TYPE) VDR201 1-801-862-11 VARISTOR (CHIP TYPE) VDR303 1-801-862-11 VARISTOR (CHIP TYPE) VDR401 1-801-862-11 VARISTOR (CHIP TYPE) VDR402 1-801-862-11 VARISTOR (CHIP TYPE) Ref. No. Part No. Description Remark MAIN www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 32 D-F20 Ref. No. Part No. Description Remark MAIN The components identified by mark 0 or dotted line with mark 0 are critical for safety. Replace only with part number specified. VDR601 1-801-862-11 VARISTOR (CHIP TYPE) VDR602 1-801-862-11 VARISTOR (CHIP TYPE) < VIBRATOR > X1 1-781-142-11 FILTER, CERAMIC (10.7MHz) X61 1-760-130-11 VIBRATOR, CRYSTAL (75kHz) X601 1-795-101-21 VIBRATOR, CERAMIC (16.9MHz) ************************************************************* MISCELLANEOUS *************** 0108 X-4952-506-1 PICK-UP BLOCK, OPTICAL (DAX-23E) M501 A-3328-627-A MOTOR ASSY, SLED (SLED) M502 A-3328-759-A MOTOR ASSY, TURNTABLE (SPINDLE) ************************************************************* ACCESSORIES & PACKING MATERIALS ******************************** 3-232-538-11 MANUAL, INSTRUCTION (ENGLISH) 8-953-342-93 HEADPHONE MDR-24 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 33 D-F20 MEMO www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 34 D-F20 REVISION HISTORY Clicking the version allows you to jump to the revised page. Also, clicking the version at the upper right on the revised page allows you to jump to the next revised page. Ver. Date Description of Revision 1.0 2001. 05 New www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com
