SERVICE MANUAL DVD AUDIO-VIDEO / SUPER AUDIO CD PLAYER MODEL DVD-1920/756 TOKYO, JAPAN Denon Brand Company, D&M Holdings Inc. Some illustrations using in this service manual are slightly different from the actual set. ● Please use this service manual with referring to the operating instructions without fail. ● For purposes of improvement, specifications and design are subject to change without notice. ● ●　本文中に使用しているイラストは、説明の都合上現物 　　と多少異なる場合があります。 ●　修理の際は、必ず取扱説明書を参照の上、作業を行っ 　　てください。 サービスをおこなう前に、このサービスマニュアルを 必ずお読みください。本機は、火災、感電、けがなど に対する安全性を確保するために、さまざまな配慮を おこなっており、また法的には「電気用品安全法」に もとづき、所定の許可を得て製造されております。 従ってサービスをおこなう際は、これらの安全性が維 持されるよう、このサービスマニュアルに記載されて いる注意事項を必ずお守りください。 ●　本機の仕様は性能改良のため、予告なく変更すること 　　があります。 ●　補修用性能部品の保有期間は、製造打切後8年です。 注　意 X0247 V.02 DE/CDM 0508 For U.S.A. & Canada model Ver. 2 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 2 DVD-1920/756 TABLE OF CONTENTS SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 LASER BEAM SAFETY PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 IMPORTANT SAFETY PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 STANDARD NOTES FOR SERVICING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 CABINET DISASSEMBLY INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11 HOW TO INITIALIZE THE DVD PLAYER. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15 FIRMWARE RENEWAL MODE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16 TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18 BLOCK DIAGRAMS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25 SCHEMATIC DIAGRAMS / CBA'S AND TEST POINTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31 WAVEFORMS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45 WIRING DIAGRAM. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46 LEAD IDENTIFICATIONS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47 EXPLODED VIEWS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48 PARTS LIST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50 Manufactured under license from Dolby Laboratories. “Dolby” and the double-D symbol are trademarks of Dolby Laboratories. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 3 DVD-1920/756 SPECIFICATIONS Notes: 1. All Items are measured without pre-emphasis unless otherwise specified. 2. Power supply: AC 120 V, 60 Hz 3. Ambient Temperature: +25 °C Item Conditions Unit Nominal Limit 1. Video Output 75 Ω load Vpp 1.0 ± 0.1 2. Coaxial Digital Out 75 Ω load mVpp 500 ± 50 3. Audio (PCM) 3-1. Output Level 1 kHz, 0 dB, 47k Ω load Vrms 2.0 3-2. S/N 47k Ω load dB 115 3-3. Freq. Response DVD fs = 48 kHz ± 0.5 dB, 47k Ω load Hz 20 ~ 22 k CD fs = 44.1 kHz ± 0.5 dB, 47k Ω load Hz 20 ~ 20 k 3-4. THD+N DVD, CD 1 kHz, 0 dB, 47k Ω load % 0.004 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 4 DVD-1920/756 LASER BEAM SAFETY PRECAUTIONS This DVD player uses a pickup that emits a laser beam. The laser beam is emitted from the location shown in the figure. When checking the laser diode, be sure to keep your eyes at least 30 cm away from the pickup lens when the diode is turned on. Do not look directly at the laser beam. CAUTION: Use of controls and adjustments, or doing procedures other than those specified herein, may result in hazardous radiation exposure. Location: Top of DVD mechanism. Do not look directly at the laser beam coming from the pickup or allow it to strike against your skin. Drive Mechanism Assembly Laser Beam Radiation Laser Pickup Turntable LASER RADIATION WHEN OPEN. DO NOT STARE INTO BEAM. CAUTION www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 5 DVD-1920/756 IMPORTANT SAFETY PRECAUTIONS Product Safety Notice Some electrical and mechanical parts have special safety-related characteristics which are often not evident from visual inspection, nor can the protection they give necessarily be obtained by replacing them with components rated for higher voltage, wattage, etc. Parts that have special safety characteristics are identified by a ! on schematics and in parts lists. Use of a substitute replacement that does not have the same safety characteristics as the recommended replacement part might create shock, fire, and/or other hazards. The Product’s Safety is under review continuously and new instructions are issued whenever appropriate. Prior to shipment from the factory, our products are carefully inspected to confirm with the recognized product safety and electrical codes of the countries in which they are to be sold. However, in order to maintain such compliance, it is equally important to implement the following precautions when a set is being serviced. Precautions during Servicing A. Parts identified by the ! symbol are critical for safety. Replace only with part number specified. B. In addition to safety, other parts and assemblies are specified for conformance with regulations applying to spurious radiation. These must also be replaced only with specified replacements. Examples: RF converters, RF cables, noise blocking capacitors, and noise blocking filters, etc. C. Use specified internal wiring. Note especially: 1) Wires covered with PVC tubing 2) Double insulated wires 3) High voltage leads D. Use specified insulating materials for hazardous live parts. Note especially: 1) Insulation tape 2) PVC tubing 3) Spacers 4) Insulators for transistors E. When replacing AC primary side components (transformers, power cord, etc.), wrap ends of wires securely about the terminals before soldering. F. Observe that the wires do not contact heat producing parts (heat sinks, oxide metal film resistors, fusible resistors, etc.). G. Check that replaced wires do not contact sharp edges or pointed parts. H. When a power cord has been replaced, check that 5 - 6 kg of force in any direction will not loosen it. I. Also check areas surrounding repaired locations. J. Be careful that foreign objects (screws, solder droplets, etc.) do not remain inside the set. K. Crimp type wire connector The power transformer uses crimp type connectors which connect the power cord and the primary side of the transformer. When replacing the transformer, follow these steps carefully and precisely to prevent shock hazards. Replacement procedure 1) Remove the old connector by cutting the wires at a point close to the connector. Important: Do not re-use a connector. (Discard it.) 2) Strip about 15 mm of the insulation from the ends of the wires. If the wires are stranded, twist the strands to avoid frayed conductors. 3) Align the lengths of the wires to be connected. Insert the wires fully into the connector. 4) Use a crimping tool to crimp the metal sleeve at its center. Be sure to crimp fully to the complete closure of the tool. L. When connecting or disconnecting the internal connectors, first, disconnect the AC plug from the AC outlet. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 6 DVD-1920/756 Safety Check after Servicing Examine the area surrounding the repaired location for damage or deterioration. Observe that screws, parts, and wires have been returned to their original positions. Afterwards, do the following tests and confirm the specified values to verify compliance with safety standards. 1. Clearance Distance When replacing primary circuit components, confirm specified clearance distance (d) and (d’) between soldered terminals, and between terminals and surrounding metallic parts. (See Fig. 1) Table 1: Ratings for selected area Note: This table is unofficial and for reference only. Be sure to confirm the precise values. 2. Leakage Current Test Confirm the specified (or lower) leakage current between B (earth ground, power cord plug prongs) and externally exposed accessible parts (RF terminals, antenna terminals, video and audio input and output terminals, microphone jacks, earphone jacks, etc.) is lower than or equal to the specified value in the table below. Measuring Method (Power ON): Insert load Z between B (earth ground, power cord plug prongs) and exposed accessible parts. Use an AC voltmeter to measure across the terminals of load Z. See Fig. 2 and the following table. Table 2: Leakage current ratings for selected areas Note: This table is unofficial and for reference only. Be sure to confirm the precise values. AC Line Voltage Clearance Distance (d), (d’) 120 V ≥ 3.2 mm (0.126 inches) AC Line Voltage Load Z Leakage Current (i) Earth Ground (B) to: 120 V 0.15 µF CAP. & 1.5 kΩ RES. Connected in parallel i ≤ 0.5 mA Peak Exposed accessible parts Chassis or Secondary Conductor d d' Primary Circuit Terminals Fig. 1 AC Voltmeter (High Impedance) Exposed Accessible Part B Earth Ground Power Cord Plug Prongs Z Fig. 2 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 7 DVD-1920/756 STANDARD NOTES FOR SERVICING Circuit Board Indications 1. The output pin of the 3 pin Regulator ICs is indicated as shown. 2. For other ICs, pin 1 and every fifth pin are indicated as shown. 3. The 1st pin of every male connector is indicated as shown. Instructions for Connectors 1. When you connect or disconnect the FFC (Flexible Foil Connector) cable, be sure to first disconnect the AC cord. 2. FFC (Flexible Foil Connector) cable should be inserted parallel into the connector, not at an angle. Pb (Lead) Free Solder When soldering, be sure to use the Pb free solder. How to Remove / Install Flat Pack-IC 1. Removal With Hot-Air Flat Pack-IC Desoldering Machine: 1. Prepare the hot-air flat pack-IC desoldering machine, then apply hot air to the Flat Pack-IC (about 5 to 6 seconds). (Fig. S-1-1) 2. Remove the flat pack-IC with tweezers while applying the hot air. 3. Bottom of the flat pack-IC is fixed with glue to the CBA; when removing entire flat pack-IC, first apply soldering iron to center of the flat pack-IC and heat up. Then remove (glue will be melted). (Fig. S-1-6) 4. Release the flat pack-IC from the CBA using tweezers. (Fig. S-1-6) CAUTION: 1. The Flat Pack-IC shape may differ by models. Use an appropriate hot-air flat pack-IC desoldering machine, whose shape matches that of the Flat Pack-IC. 2. Do not supply hot air to the chip parts around the flat pack-IC for over 6 seconds because damage to the chip parts may occur. Put masking tape around the flat pack-IC to protect other parts from damage. (Fig. S-1-2) Top View Out In Bottom View Input 5 10 Pin 1 Pin 1 FFC Cable Connector CBA * Be careful to avoid a short circuit. Fig. S-1-1 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 8 DVD-1920/756 3. The flat pack-IC on the CBA is affixed with glue, so be careful not to break or damage the foil of each pin or the solder lands under the IC when removing it. With Soldering Iron: 1. Using desoldering braid, remove the solder from all pins of the flat pack-IC. When you use solder flux which is applied to all pins of the flat pack-IC, you can remove it easily. (Fig. S-1-3) 2. Lift each lead of the flat pack-IC upward one by one, using a sharp pin or wire to which solder will not adhere (iron wire). When heating the pins, use a fine tip soldering iron or a hot air desoldering machine. (Fig. S-1-4) 3. Bottom of the flat pack-IC is fixed with glue to the CBA; when removing entire flat pack-IC, first apply soldering iron to center of the flat pack-IC and heat up. Then remove (glue will be melted). (Fig. S-1-6) 4. Release the flat pack-IC from the CBA using tweezers. (Fig. S-1-6) Hot-air Flat Pack-IC Desoldering Machine CBA Flat Pack-IC Tweezers Masking Tape Fig. S-1-2 Flat Pack-IC Desoldering Braid Soldering Iron Fig. S-1-3 Fine Tip Soldering Iron Sharp Pin Fig. S-1-4 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 9 DVD-1920/756 With Iron Wire: 1. Using desoldering braid, remove the solder from all pins of the flat pack-IC. When you use solder flux which is applied to all pins of the flat pack-IC, you can remove it easily. (Fig. S-1-3) 2. Affix the wire to a workbench or solid mounting point, as shown in Fig. S-1-5. 3. While heating the pins using a fine tip soldering iron or hot air blower, pull up the wire as the solder melts so as to lift the IC leads from the CBA contact pads as shown in Fig. S-1-5. 4. Bottom of the flat pack-IC is fixed with glue to the CBA; when removing entire flat pack-IC, first apply soldering iron to center of the flat pack-IC and heat up. Then remove (glue will be melted). (Fig. S-1-6) 5. Release the flat pack-IC from the CBA using tweezers. (Fig. S-1-6) Note: When using a soldering iron, care must be taken to ensure that the flat pack-IC is not being held by glue. When the flat pack-IC is removed from the CBA, handle it gently because it may be damaged if force is applied. 2. Installation 1. Using desoldering braid, remove the solder from the foil of each pin of the flat pack-IC on the CBA so you can install a replacement flat pack-IC more easily. 2. The “ ● ” mark on the flat pack-IC indicates pin 1. (See Fig. S-1-7.) Be sure this mark matches the 1 on the PCB when positioning for installation. Then presolder the four corners of the flat pack-IC. (See Fig. S-1-8.) 3. Solder all pins of the flat pack-IC. Be sure that none of the pins have solder bridges. To Solid Mounting Point Soldering Iron Iron Wire or Hot Air Blower Fig. S-1-5 Fine Tip� Soldering Iron CBA Flat Pack-IC Tweezers Fig. S-1-6 Example : Pin 1 of the Flat Pack-IC is indicated by a " " mark. Fig. S-1-7 Presolder CBA Flat Pack-IC Fig. S-1-8 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 10 DVD-1920/756 Instructions for Handling Semi- conductors Electrostatic breakdown of the semi-conductors may occur due to a potential difference caused by electrostatic charge during unpacking or repair work. 1. Ground for Human Body Be sure to wear a grounding band (1 MΩ) that is properly grounded to remove any static electricity that may be charged on the body. 2. Ground for Workbench Be sure to place a conductive sheet or copper plate with proper grounding (1 MΩ) on the workbench or other surface, where the semi-conductors are to be placed. Because the static electricity charge on clothing will not escape through the body grounding band, be careful to avoid contacting semi-conductors with your clothing. CBA Grounding Band Conductive Sheet or Copper Plate 1MΩ 1MΩ CBA www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 11 DVD-1920/756 CABINET DISASSEMBLY INSTRUCTIONS 1. Disassembly Flowchart This flowchart indicates the disassembly steps to gain access to item(s) to be serviced. When reassembling, follow the steps in reverse order. Bend, route, and dress the cables as they were originally. 2. Disassembly Method Note: (1) Identification (location) No. of parts in the figures (2) Name of the part (3) Figure Number for reference (4) Identification of parts to be removed, unhooked, unlocked, released, unplugged, unclamped, or desoldered. P = Spring, L = Locking Tab, S = Screw, CN = Connector * = Unhook, Unlock, Release, Unplug, or Desolder e.g. 2(S-2) = two Screws (S-2), 2(L-2) = two Locking Tabs (L-2) (5) Refer to “Reference Notes.” About tightening screws When tightening screws, tighten them with the following torque. ID/ Loc. No. Part Removal Fig. No. Remove/*Unhook/ Unlock/Release/ Unplug/Desolder Note [1] Top Cover D1 5(S-1) --- [2] Front Unit D2 *2(L-1), *2(L-2), *3(L-3), *CN2001 1 [3] Tray Panel D2 *2(L-4) 1 [4] Function CBA D3 6(S-2) --- [5] Front Assembly D3 ---------- --- [6] Rear Panel D4 8(S-3), (S-4), (S-5) --- [7] DVD Main CBA Unit D5 2(S-6A), (S-6B), *CN201, *CN301, *CN401, *CN601, *CNS01 2 [8] 5.1ch Amp CBA D5 (S-6), 2(L-5), *CN7101 --- [9] Jack PCB Holder D5 2(S-7) --- [10] DVD Mechanism D5 D6 4(S-8) 2 3 [11] LED CBA D7 *CN2102 --- [12] AV CBA D7 4(S-9), (S-10) --- [1] Top Cover [5] Front Assembly [2] Front Unit [3] Tray Panel [6] Rear Panel [13] Loader Base [15] Main PCB Holder [7] DVD Main CBA Unit [10] DVD Mechanism [14] Power PCB Holder [11] LED CBA [4] Function CBA [8] 5.1ch Amp CBA [9] Jack PCB Holder [12] AV CBA [13] Loader Base D8 4(S-11) --- [14] Power PCB Holder D8 2(S-12) --- [15] Main PCB Holder D8 (S-13) --- ↓ (1) ↓ (2) ↓ (3) ↓ (4) ↓ (5) Screws Torque (S-1), (S-2), (S-3), (S-4), (S-5), (S-6A), (S-7), (S-8), (S-9), (S-10), (S-11), (S-12), (S-13) 0.45 ± 0.05 N·m (S-6B) 0.38 ± 0.04 N·m ID/ Loc. No. Part Removal Fig. No. Remove/*Unhook/ Unlock/Release/ Unplug/Desolder Note www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 12 DVD-1920/756 Reference Notes 1. CAUTION 1: Locking Tabs (L-1), (L-2), (L-3) and (L-4) are fragile. Be careful not to break them. 1) Release two Locking Tabs (L-1), then release two Locking Tabs (L-2). 2) Release three Locking Tabs (L-3). 3) Disconnect connector CN2001 and remove the Front Assembly. 2. CAUTION 2: Electrostatic breakdown of the laser diode in the optical system block may occur as a potential difference caused by electrostatic charge accumulated on cloth, human body etc., during unpacking or repair work. To avoid damage of pickup follow next procedures. 1) Short the three short lands of FPC cable with solder before removing the FFC cable (CN201) from it. If you disconnect the FFC cable (CN201), the laser diode of pickup will be destroyed. (Fig. D5) 2) Disconnect Connectors (CN301), (CN401), (CN601) and (CNS01). Remove two screws (S-6A) and (S-6B), and lift the DVD Main CBA Unit. (Fig. D5) 3. CAUTION 3: When reassembling, confirm the FFC cable (CN201) is connected completely. Then remove the solder from the three short lands of FPC cable. (Fig. D5) Fig. D1 [1] Top Cover (S-1) (S-1) (S-1) [2] Front Unit [3] Tray Panel CN2001 (L-1) (L-1) (L-2) (L-2) (L-4) (L-4) (L-3) Fig. D2 [4] Function CBA [5] Front Assembly (S-2) (S-2) Fig. D3 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 13 DVD-1920/756 [6] Rear Panel (S-5) (S-3) (S-3) (S-4) (S-3) Fig. D4 (S-6A) (S-6B) (S-6) (S-7) [9] Jack PCB Holder [8] 5.1ch Amp CBA [7] DVD Main CBA Unit CN401 CN301 (L-5) A Fig. D5 View for A Short the three short lands by soldering. (Either of two places.) Connector CNS01 CN7101 CN201 CN601 Fig. D6 [10] DVD Mechanism (S-8) (S-8) [12] AV CBA [11] LED CBA (S-9) (S-9) (S-10) CN2102 Fig. D7 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 14 DVD-1920/756 3. How to Eject Manually 1. Remove the Top Cover. 2. Rotate the roulette in the direction of the arrow as shown below. [13] Loader Base [15] Main PCB Holder (S-11) Fig. D8 (S-11) (S-13) [14] Power PCB Holder (S-12) A View for A Rotate this roulette in the direction of the arrow www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 15 DVD-1920/756 HOW TO INITIALIZE THE DVD PLAYER To put the program back at the factory-default, initialize the DVD player as the following procedure. 1. Press [1], [2], [3], [4], and [DISPLAY] buttons on the remote control unit in that order. Fig. a appears on the screen. 2. Press [CLEAR] button on the remote control unit. Fig. b appears on the screen. When “OK” appears on the screen, the factory default will be set. 3. To exit this mode, press [POWER OFF] button. MODEL : ******* Version : *.** Region : * EXIT: POWER EEPROM CLEAR : CLEAR Fig. a "*******" differ depending on the models. MODEL : ******* Version : *.** Region : * EEPROM CLEAR : OK EXIT: POWER EEPROM CLEAR : CLEAR "*******" differ depending on the models. Fig. b www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 16 DVD-1920/756 FIRMWARE RENEWAL MODE 1. Turn the power on and remove the disc on the tray. 2. To put the DVD player into version up mode, press [9], [8], [7], [6], and [SEARCH MODE] buttons on the remote control unit in that order. The tray will open automatically. Fig. a appears on the screen and Fig. b appears on the VFD. The DVD player can also enter the version up mode with the tray open. In this case, Fig. a will be shown on the screen while the tray is open. 3. Load the disc for version up. 4. The DVD player enters the F/W version up mode automatically. Fig. c appears on the screen and Fig. d appears on the VFD. If you enter the F/W for different models, “Disc Error” will appear on the screen, then the tray will open automatically. The appearance shown in (*1) of Fig. c is described as follows: 5. After programming is finished, the tray opens automatically. Fig. e appears on the screen and the checksum in (*2) of Fig. e appears on the VFD (Fig. f). At this time, no button is available. 6. Remove the disc on the tray. 7. Unplug the AC cord from the AC outlet. Then plug it again. 8. Turn the power on by pressing the [POWER ON] button and the tray will close. 9. Press [1], [2], [3], [4], and [DISPLAY] buttons on the remote control unit in that order. Fig. g appears on the screen. No. Appearance State 1 Reading... Sending files into the memory 2 Erasing... Erasing previous version data 3 Programming... Writing new version data F/W Version Up Mode Model No : ******* VERSION : *.** Please insert a DISC for F/W Version Up. EXIT: POWER "*******" differ depending on the models. Fig. a Version Up Mode Screen Fig. b VFD in Version Up Mode VERSION : ************.ab6 Reading... F/W Version Up Mode Model No : ******* VERSION : *.** Fig. c Programming Mode Screen "*******" differ depending on the models. (*1) Fig. d VFD in Programming Mode (Example) VERSION : ************.ab6 Completed SUM : 7ABC F/W Version Up Mode Model No : ******* VERSION : *.** "*******" differ depending on the models. Fig. e Completed Program Mode Screen (*2) Fig. f VFD upon Finishing the Programming Mode (Example) MODEL : ******* Version : *.** Region : * EXIT: POWER EEPROM CLEAR : CLEAR Fig. g "*******" differ depending on the models. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 17 DVD-1920/756 10. Press [CLEAR] button on the remote control unit. Fig. h appears on the screen. When “OK” appears on the screen, the factory default will be set. Then the firmware renewal mode is complete. 11. To exit this mode, press [POWER OFF] button. MODEL : ******* Version : *.** Region : * EEPROM CLEAR : OK EXIT: POWER EEPROM CLEAR : CLEAR "*******" differ depending on the models. Fig. h www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 18 DVD-1920/756 TROUBLESHOOTING FLOW CHART NO.2 The fuse blows out. After servicing, replace the fuse. Check the presence that the primary component is leaking or shorted and service it if defective. Check the presence that the rectifying diode or circuit is shorted in each rectifying circuit of secondary side, and service it if defective. FLOW CHART NO.3 When the output voltage fluctuates. Yes No FLOW CHART NO.4 When buzz sound can be heard in the vicinity of power circuit. Check if there is any short-circuit on the rectifying diode and the circuit in each rectifying circuit of the secondary side, and service it if defective. (D1003, D1006, D1008, D1016, D1030, IC1002, Q1002, Q1004, Q1005, Q1011, Q1014, Q1020) Does the photo coupler circuit on the secondary side operate normally? Check IC1001, D1012, D1024 and their periphery, and service it if defective. Check IC1001, IC1006, D1048 and their periphery, and service it if defective. FLOW CHART NO.5 -FL is not outputted. Is approximately -23V voltage supplied to the anode of D1003? Check D1003 and periphery circuit, and service it if defective. Check if there is any leak or short-circuit on the loaded circuit, and service it if defective. Yes No FLOW CHART NO.1 The power cannot be turned on. Is the fuse normal? Is normal state restored when once unplugged power cord is plugged again after several seconds? Is the EV +3.3V line voltage normal? See FLOW CHART No.2 Check if there is any leak or short-circuiting on the primary circuit component, and service it if defective. (Q1001, Q1003, Q1008, T1001, D1001, D1002, D1004, D1005, D1011, C1003, C1005) Check each rectifying circuit of the secondary circuit and service it if defective. Yes Yes Yes No No No www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 19 DVD-1920/756 FLOW CHART NO.7 P-ON+5V is not outputted. (EV+10V is outputted normally.) Is the "H" signal inputted into the base of Q1004? Replace Q1004. Replace Q1014. Check R1068 and D1046, and service it if defective. Yes No Is the "H" signal inputted into the base of Q1014? Check D1047, R1069, R1098 and the periphery circuit, and service it if defective. No FLOW CHART NO.8 P-ON+3.3V is not outputted. (P-ON+10V is outputted normally.) Is 3.3V voltage supplied to the collector of Q1011? Replace Q1011 or R1067. Check D1008, C1007, C1038, L1007, and the periphery circuit, and service it if defective. Yes No FLOW CHART NO.9 EV+5V is not outputted. Is EV+10V outputted normally? Refer to "FLOW CHART NO.6" Yes Yes No FLOW CHART NO.10 EV+1.2V is not outputted. Is 2.5V voltage supplied to Pin(3) of IC1002? Replace IC1002. Check D1006, C1014, L1008 and the periphery circuit, and service it if defective. Yes No FLOW CHART NO.6 P-ON+10V (EV+10V) is not outputted. Is 10V voltage supplied to the emitter of Q1002? Is the voltage of base on Q1002 lower than the voltage of emitter on Q1002 when turning the power on? Replace Q1002. Check D1030, D1048, C1035, C1048, L1009, and the periphery circuit, and service it if defective. Check Q1016 and PWRCON line and service it if defective. Yes Yes No No FLOW CHART NO.11 EV+3.3V is not outputted. Is 3.3V voltage supplied to the collector of Q1020? Check D1008, C1007, C1038, L1007 and the periphery circuit, and service it if defective. Yes No Is the "H" signal inputted into the base of Q1020? Yes Replace Q1020. Check R1050 and the periphery circuit, and service it if defective. No Is EV+10V outputted normally? Yes Refer to "FLOW CHART NO.6" No www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 20 DVD-1920/756 Yes No FLOW CHART NO.13 The key operation is not functioning. Are the contact point and the installation state of the key switches (SW2101, SW2103-2108, SW2181-2183) normal? When pressing each switches (SW2101, SW2103-2108, SW2181-2183), do the voltage of each pin of IC2001 (shown below) increase? SW2103, 2104, 2106, 2107, 2182: IC2001 3PIN SW2101, 2105, 2108, 2181, 2183: IC2001 4PIN Check the switches (SW2101, SW2103-2108, SW2181-2183) and their periphery, and service it if detective. No Re-install the switches (SW2101, SW2103-2108, SW2181-2183) correctly or replace the poor switch. Replace IC2001. Yes FLOW CHART NO.14 No operation is possible from the remote control unit. Operation is possible from the DVD, but no operation is possible from the remote control unit. Replace the infrared remote control receiver (RM2001) or replace the remote control unit. Check the line between Pin(1) terminal of receiver (RM2001) and Pin(25) of CN1001, and service it if defective. Is the "L" pulse sent out Pin(1) terminal of receiver (RM2001) when the infrared remote control is activated? Is the "L" pulse supplied to the Pin(25) of CN1001? Replace DVD Main CBA Unit. Is 5V voltage supplied to Pin(3) terminal of the infrared remote control receiver (RM2001)? Yes No Check EV+5V line and service it if defective. No No Yes Yes Yes Yes Yes Yes No No No No FLOW CHART NO.12 The fluorescent display tube does not light up. Is 3.3V voltage supplied to Pins(6,24) of IC2001? Is the voltage of approximately -20V supplied to Pin(15) of IC2001? Is there 500kHz oscillation at Pin(26) of IC2001? Are the filament voltage supplied between Pins(1, 2) and Pins(29, 30) of the fluorescent display tube? And the negative voltage applied between these pins and GND? Replace the fluorescent display tube. Check the EV+3.3V line and service it if defective. Check the -FL (-20V) line and service it if defective. Check R2002, IC2001 and their periphery, and service it if defective. Check PWRCON line, and service it if defective. Is the "H" signal inputted to base of Q1016? Check D1016, D1017, T1001, and their periphery, and service it if defective. Is -14V voltage supplied to collector of Q1005? No Yes Yes No Check Q1015, Q1016, D1055, and their periphery, and service it if defective. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 21 DVD-1920/756 FLOW CHART NO.18 [No Disc] indicated. (When the focus servo is not functioning.) FLOW CHART NO.19 [No Disc] indicated. (When the laser beam does not light up.) Replace the DVD Main CBA Unit. Replace the DVD Mechanism. No Yes Replace the DVD Main CBA Unit. Replace the DVD Mechanism. No Yes No improvement can be found. Original DVD Main CBA Unit is poor. No improvement can be found. Original DVD Main CBA Unit is poor. FLOW CHART NO.17 [No Disc] indicated. (When the focus error occurs.) Replace the DVD Main CBA Unit. No improvement can be found. Original DVD Main CBA Unit is poor. Replace the DVD Mechanism. No Yes Yes FLOW CHART NO.16 The disc tray cannot be opened and closed. Replace the DVD Main CBA Unit. Original DVD Main CBA Unit is poor. Replace the DVD Mechanism. No improvement can be found. No Yes FLOW CHART NO.15 The disc tray cannot be opened and closed. (It can be done using the remote control unit.) Is the normal control voltage inputted to Pin(4) of IC2001? Refer to "FLOW CHART NO.13" Refer to "FLOW CHART NO.16" Replace the "OPEN/CLOSE" button (SW2108). No www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 22 DVD-1920/756 Is 5V voltage applied to the Pin(1, 24) of IC1402 and Pin(4) of IC1403? Replace IC1402 or IC1403. Check P-ON+5V line and service it if detective. Are the video signals outputted to each pin of IC1402 or IC1403? Yes No Yes Yes No IC1402 18PIN S-Y(I/P) IC1402 15PIN Cb/Pb IC1402 13PIN Cr/Pr IC1403 5PIN S-Y(I) IC1403 6PIN CVBS IC1403 7PIN S-C Check the periphery of JK1404 from Pins (13, 15, 18) of IC1402 and service it if detective. Check the periphery of JK1404 from Pin(6) of IC1403 and service it if detective. Check the periphery of JK1401 from Pin (5) of IC1403 and service it if detective. Check the periphery of JK1401 from Pin (7) of IC1403 and service it if detective. Are the video signals outputted to the specific output terminal? Are the component video signals outputted to the VIDEO OUT terminal (JK1404)? Are the luminance signals outputted to the S-OUT terminal (JK1401)? Are the chroma signals outputted to the S-OUT terminal (JK1401)? No No No No Are the composite video signals outputted to the VIDEO OUT terminal (JK1404)? FLOW CHART NO.21 Picture does not appear normally. Set the disc on the disc tray, and playback. Are the video signals outputted to each pin of CN1601 on the AV CBA? Replace the DVD Main CBA Unit or DVD Mechanism. Check the line between each pin of CN1601 and each pin of IC1402 or IC1403 on the AV CBA, and service it if detective. CN1601 3PIN → IC1403 3PIN S-Y(I) CN1601 10PIN → IC1403 1PIN S-C CN1601 8PIN → IC1402 6PIN S-Y(I/P) CN1601 6PIN → IC1402 9PIN Cb/Pb CN1601 4PIN → IC1402 11PIN Cr/Pr Are the video signals shown above inputted into each pin of IC1402 or IC1403? Yes No No CN1601 3PIN S-Y(I) CN1601 4PIN Cr/Pr CN1601 6PIN Cb/Pb CN1601 8PIN S-Y(I/P) CN1601 10PIN S-C IC1403 3PIN S-Y(I) IC1403 1PIN S-C IC1402 6PIN S-Y(I/P) IC1402 9PIN Cb/Pb IC1402 11PIN Cr/Pr FLOW CHART NO.20 Both functions of picture and sound do not operate normally. Replace the DVD Main CBA Unit. Replace the DVD Mechanism. No Yes No improvement can be found. Original DVD Main CBA Unit is poor. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 23 DVD-1920/756 FLOW CHART NO.22 Audio is not outputted normally. Set the disc on the disc tray, and playback. Are the analog audio signals outputted to each pin of CN1601 on AV CBA? Is the "H" level mute signal outputted to CN1601 on AV CBA ? CN1601 13PIN AUDIO(L) CN1601 15PIN AUDIO(R) CN1601 14PIN AUDIO(R)-MUTE CN1601 19PIN AUDIO(L)-MUTE IC1201 1PIN AUDIO(L) IC1201 7PIN AUDIO(R) IC1201 2PIN AUDIO(L) IC1201 6PIN AUDIO(R) Replace the DVD Main CBA Unit or DVD Mechanism. Replace the DVD Main CBA Unit or DVD Mechanism. Replace IC1201. Check the periphery between Pins(1,7) of IC1201 and JK1404, and service it if detective. Check each line between each pin of CN1601 and each pin of IC1201 on AV CBA, and service it if detective. CN1601 13PIN → IC1201 2PIN AUDIO(L) CN1601 15PIN → IC1201 6PIN AUDIO(R) Are the analog audio signals inputted to each pin of IC1201. Are the analog audio signals outputted to each pin of IC1201? Are the audio signals outputted to the specific output terminal? Are the audio signals outputted to the audio terminal (JK1404)? Yes Yes Yes Yes No No No No No www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 24 DVD-1920/756 FLOW CHART NO.23 Audio is not outputted. (JK7101) Set the disc (with 5.1ch Audio) on the disc tray, and playback. Are the analog audio signals outputted to each pin of CN7102 on 5.1ch Amp CBA. CN7102 15PIN FRONT(L) CN7102 13PIN FRONT(R) CN7102 11PIN SURROUND(L) CN7102 9PIN SURROUND(R) CN7102 7PIN CENTER CN7102 5PIN SUBWOOFER IC7301 2, 6PIN FRONT(L/R) IC7401 2, 6PIN SURROUND(L/R) IC7501 2, 6PIN CENTER/SUBWOOFER Replace the DVD Main CBA or DVD Mechanism. Replace ICs (IC7301, IC7401 or IC7501). Check each line between each pin of CN7102 and each pin of IC7301,IC7401 and IC7501 and service it if defective. CN7102 15,13PIN → IC7301 2,6PIN FRONT(L/R) CN7102 11,9PIN → IC7401 2,6PIN SURROUND(L/R) CN7102 7,5PIN → IC7501 2,6PIN CENTER/SUBWOOFER Are the analog audio signals inputted to each pin of IC7301, IC7401 and IC7501. Are the analog audio signals outputted to each pin of IC7301, IC7401 and IC7501. IC7301 1,7PIN FRONT(L/R) IC7401 1,7PIN SURROUND(L/R) IC7501 1,7PIN CENTER/SUBWOOFER Yes Yes No No No Check each line and service it if defective. No Replace the DVD Main CBA Unit. No Yes Do the mute signals of CN7102 on 5.1ch Amp CBA become to "H" level? FRONT(L) → CN7102 14PIN FRONT(R) → CN7102 12PIN SURROUND(L) → CN7102 10PIN SURROUND(R) → CN7102 8PIN CENTER → CN7102 6PIN SUBWOOFER → CN7102 4PIN Yes Is the analog audio signal of each line outputted to each terminal of JK7101 (as shown below) ? IC7301 1PIN → JK7101 FRONT(L) IC7301 7PIN → JK7101 FRONT(R) IC7401 1PIN → JK7101 SURROUND(L) IC7401 7PIN → JK7101 SURROUND(R) IC7501 1PIN → JK7101 CENTER IC7501 7PIN → JK7101 SUBWOOFER www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 25 DVD-1920/756 BLOCK DIAGRAMS System Control / Servo Block Diagram CN401 CN1001 12 7 8 9 10 11 REMOTE SENSOR RM2001 JK3501 1G 7G ~ 23 17 ~ a/KEY-1 b/KEY-2 c/KEY-3 d/KEY-4 e K1 K2 GRID FIP SEGMENT FL2001 IC2001 (FRONT PANEL CONTROL) 13 14 16 3 4 f/KEY-6 g h i KEY MATRIX CN2001 CN2101 KEY-1 6 8 KEY-2 4 6 KEY-3 5 7 KEY-4 7 9 Q2086 K2 2 4 K1 3 5 KEY-6 1 3 REMOCON -IN REMOCON -OUT 74 FP-DIN 22 28 FP-DIN FP-DIN 22 253 FP-STB 23 2 FP-STB FP-STB 23 73 FP-DOUT 24 27 FP-DOUT FP-DOUT 24 75 FP-CLK 21 1 FP-CLK FP-CLK 21 71 REMOTE 25 REMOTE 25 5 HDMI 26 HDMI 26 AV CBA FUNCTION CBA IC3510 7 1 AMP SW2101 POWER CN2002 CN2102 D2182 POWER-LED 2 2 STANDBY-LED 3 3 KEY-2 5 5 K2 6 6 LED CBA POWER STANDBY INV-POWCON +5V TO POWER SUPPLY BLOCK DIAGRAM Q2088 Q2089 HDMI-LED 7 7 +5V D2184 HDMI IC301 (SERVO DRIVE) CN301 FG SENSOR M SLED MOTOR M SPINDLE MOTOR IC101 (MICRO CONTROLLER) +- +- +- +- +- +- +- SLED MOTOR DRIVE FOCUS ACTUATOR DRIVE SPINDLE MOTOR DRIVE TRACKING ACTUATOR DRIVE 144 TRAY-IN FG-IN SLD 91 SPDL 90 TRACKING DRIVE 145 FOCUS DRIVE 89 85 FS(+) FS(-) TS(+) TS(-) 77 ADAC-MD 78 ADAC-MC 70 ADAC-ML ADAC-MC ADAC-ML M-MUTE 72 A-MUTE ADAC-MD A-MUTE 7 M-MUTE TRAY-IN 3 SP(+) 4 SP(-) 5 TRAY-IN 6 GND 7 SL(-) 8 SL(+) 1 FG-IN VREF RESET 84 RESET IC461 2 1 +3.3V IC202 (OP AMP) 15 16 14 13 12 11 17 18 23 6 4 5 3 1 2 25 24 27 26 87 SL-AMP 139 SP-ROT +3.3V 1 2 6 7 5 3 9 8 10 13 14 12 142 FD-OFST 141 TD-OFST DRIVE CBA DVD MAIN CBA UNIT FG CBA TO DIGITAL SIGNAL PROCESS BLOCK DIAGRAM TO AUDIO BLOCK DIAGRAM ADAC-MD ADAC-MC TO SACD BLOCK DIAGRAM (AMP) 140 SL-ADS www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 26 DVD-1920/756 Digital Signal Process Block Diagram C 16 D 18 A 17 B 15 E 14 F 12 DVD-LD 8 CD-LD 10 PD-MONI 7 FS(+) 2 FS(-) 3 TS(+) 1 TS(-) 4 CN201 CN201 CN201 IC201 (SW) IC501 (SDRAM) IC101 (MICRO CONTROLLER) FS FS(+) CLK33M/36M CD/DVD FSEL CLK33M FS(-) TS(+) TS(-) TS DETECTOR CD/DVD 19 Q251,Q252 CD DVD AMP Q253,Q254 AMP 4 1 3 6 GND(DVD-PD) 6 GND(CD-PD) 5 GND(LD) 9 RF SIGNAL PROCESS CIRCUIT DVD/CD FORMATTER AUDIO I/F VIDEO I/F NTSC/PAL ENCODER DMA BCU INST. ROM 32BIT CPU DATA RAM INTERRUPT CONTROLLER WATCH DOG TIMER CPU I/F TIMER DECODER I/F CPU I/F READ MEMORY DATA RAM DSP DECODER I/O PROCESSOR INST. ROM DATA RAM INST. ROM SERIAL D/A GENERAL I/O INTERRUPT CONTROLLER TIMER WATCH DOG TIMER REMOTE CONTROL 32BIT CPU STREAM I/F EXTERNAL MEMORY I/F SDRAM ECC UMAC 117 118 116 115 133 134 131 132 129 130 126 124 125 123 86 DEBUG BCU INST RAM DATA RAM D/A 156 157 Y(I) C VIDEO-Y(I) I2C-SDA I2C-SCL I2C-SDA I2C-SCL VIDEO-C YC(0-7) 173 SD0/SPDIF 172 SD1 171 SD2 170 SD3 169 SD4 168 SD5 167 SD6 SD0/SPDIF SD1 SD2 SD3 SD4 SD5 SD6 166 SD7 194 XSHD 192 XSAK 193 SDCK XSHD XSAK SDCK 254 SACD-RESET 195 XSRQ 191 SDEF SACD-RESET XSRQ SDEF PSP-WCK SACD-READY SACD-DATA PSP-WCK SACD-READY SACD-DATA SACD-LATCH SACD-LATCH SACD SACD SDRAM DATA(0-15) SDRAM ADDRESS(0-11) SDRAM ADDRESS(0-11) 230 247 ~ 198 217 ~ 2 13 42 53 ~ ~ DATA(VIDEO/AUDIO) SIGNAL VIDEO SIGNAL DATA(AUDIO) SIGNAL 22 26 29 35 ~ ~ SDRAM DATA(0-15) PICK-UP UNIT TO SYSTEM CONTROL/SERVO BLOCK DIAGRAM TO AUDIO BLOCK DIAGRAM 27MHz OSC 27MHz CLOCK X'TAL OSC CLK GENE. X101 DVD MAIN CBA UNIT TO VIDEO BLOCK DIAGRAM TO VIDEO BLOCK DIAGRAM TO SACD BLOCK DIAGRAM TO AUDIO BLOCK DIAGRAM FDQ (0-15) FADR (0-19) FLASH ROM 29 36 38 45 ~ ~ FDQ (0-15) FADR (0-19) ~ 1 9 16 25 48 ~ 163 162 4 ICS03 10 14 7 PCM-SCLK 15 CLOCK-PULSE 3 190 TO SACD BLOCK DIAGRAM TO VIDEO BLOCK DIAGRAM IC103 (FLASH ROM) (CLOCK GENERATOR) SD7 66 67 186 CLK27M 176 183 ~ 15 81 76 80 94 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 27 DVD-1920/756 Video Block Diagram VIDEO SIGNAL DATA(AUDIO) SIGNAL R(0-7) ICF02 (SDRAM) SDRAM 91 103 ~ 2 13 31 56 74 85 ~ ~ ~ 24 27 60 66 ~ ~ 50 87 ~ ICF01 (DIGTAL VIDEO CONVERTER) ICF11 (HDTV VIDEO ENCODER) SDRAM DATA(0-31) SDRAM ADDRESS(0-10) NOISE REDUCER, DEINTERLACER,FRAME RATE CONVERTER AND SDRAM INTERFACE INPUT PROCESOR WITH AUTO SYNC AND AUTO ADJUST 196 CLOCK GENERATION PLLS OUTPUT PROCESSOR WITH SYNC GENERATION AND DIGTAL ANALOG CONVERTERS VERTICAL AND HORIZONTAL ENHANCERS VERTICAL AND HORIZONTAL SCALERS YC(0-7) YC(0-7) YC(0-7) 199 205 ~ YC(0-7) 140 145 ~ 148 155 ~ 136 137 130 135 ~ 126 127 49 56 ~ 57 58 ~ 61 65 ~ 75 79 ~ 68 70 ~ VIDEO DATA CAPTURE BLOCK AUDIO DATA CAPTURE BLOCK B(0-7) G(0-7) R(0-7) B(0-7) G(0-7) R(0-7) G(0-7) 119 V-SYNC 118 H-SYNC V-SYNC H-SYNC 122 HDMI-DE 125 VCLK 2 1 66 80 XOR MASK PANEL LINK TRANSMITTER 8 8 VIDEO-Y(I/P) 10 10 VIDEO-C 6 6 VIDEO-Cb/Pb 4 4 VIDEO-Cr/Pr VIDEO-C JK1401 S-VIDEO OUT 3 4 2 1 Y C WF1 WF3 IC1402 (VIDEO DRIVER) 4dB AMP 2dB AMP LPF DRIVER D/A 15 4dB AMP 2dB AMP LPF DRIVER 9 13 4dB AMP 2dB AMP LPF DRIVER 11 6 13 IC1403 (VIDEO DRIVER) 4dB AMP 2dB AMP LPF DRIVER 2dB AMP DRIVER 4dB AMP 2dB AMP LPF DRIVER 3 1 5 6 7 1 1 VIDEO-Y(I) CN601 CN1601 VIDEO-Y(I) WF2 TO DIGITAL SIGNAL PROCESS BLOCK DIAGRAM DVD MAIN CBA UNIT AV CBA COMPOSITE VIDEO OUT VIDEO-Cb/Pb OUT VIDEO-Y OUT VIDEO-Cr/Pr OUT JK1404 TO AUDIO BLOCK DIAGRAM HDCP ENCRYPTION ENGINE HDCP KEYS EEPROM REGISTERS AND CONFIGURATION T.M.D.S DATA2- CNF01 3 1 6 4 HDMI-CONNECTOR T.M.D.S DATA2+ 9 7 10 12 T.M.D.S DATA1- T.M.D.S DATA1+ T.M.D.S DATA0- T.M.D.S DATA0+ T.M.D.S CLOCK+ T.M.D.S CLOCK- 35 36 32 33 29 30 27 26 ICF09 (HDMI INTERFACE) 18 6 5 2 3 7 1 ICF04 (3.3V<-->5V CONVERTER) 16 15 DDC DATA DDC CLOCK I2C SLAVE 19 20 45 46 I2C-SCL I2C-SDA I2C-SCL I2C-SDA I2C-SCL I2C-SDA TO DIGITAL SIGNAL PROCESS BLOCK DIAGRAM 19 18 67 43 44 HPD QF01 +3.3V HOT PLUG DETECT ICF06 1 2 5 (FLIP FLOP) F/F 3 191 XTAL-IN CLOCK-PULSE 195 CLOCK-PULSE SPDIF PCM-DATA3 PCM-DATA2 PCM-DATA1 PCM-DATA0 PCM-LRCK PCM-BCK PCM-SCLK TO DIGITAL SIGNAL PROCESS BLOCK DIAGRAM 5 7 8 9 10 11 12 6 I2C-SCL I2C-SDA 39 38 37 23 24 22 21 32 63 D/A D/A HDTV VIDEO ENCODER DEMUX PLL 53-55, 58-62 4-9, 12,13 16-18, 26-30 B(0-7) R(0-7) R(0,1) G(0-7) B(2-7) G(0-7) B(2-7)/R(0,1) B(0-7) G(0-7) SDRAM DATA(0-31) SDRAM ADDRESS(0-10) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 28 DVD-1920/756 Audio Block Diagram ICS02 (AUDIO DAC) JK1202 BUFFER MUTE-ON Q1351 IC1201 Q1201 Q1202 (AMP) AUDIO(L)- OUT FUNCTION CONTROL ENHANCED MULTI-LEVEL DELTA-SIGMA MODULATOR AUDIO(R)- OUT ADAC-MD SACD-RESET ADAC-MC ADAC-ML 11 8 7 DAC LPF+AMP R-CH AUDIO(R)-MUTE A-MUTE2 SPDIF PCM-DATA3 PCM-DATA2 PCM-DATA1 PCM-DATA0 PCM-LRCK PCM-BCK PCM-SCLK 12 DAC LPF+AMP L-CH 30 DAC LPF+AMP R-CH 31 DAC LPF+AMP L-CH 28 DAC LPF+AMP R-CH 29 DAC LPF+AMP L-CH 9 DAC LPF+AMP R-CH 10 DAC LPF+AMP L-CH Q1204 PCM I/F DSD-CLK DSD-MXL DSD-MXR DSD-FL DSD-FR DSD-C DSD-SW DSD-LS DSD-RS SD6 SD5 SD2 SD3 SD1 SD4 PCM FILTER (X8 DF) IC1204 AV CBA 5.1CH AMP CBA DVD MAIN CBA UNIT JK1404 DIGITAL AUDIO OUT OPTICAL COAXIAL CN601 CN1601 13 13 AUDIO-L 15 15 AUDIO-R 14 14 AUDIO(R)-MUTE 18 18 SPDIF CNS01 CN7102 13 13 FRONT-AUDIO-R 11 11 SURROUND-L 9 9 SURROUND-R 7 7 CENTER 15 15 FRONT-AUDIO-L 5 5 SUB WOOFER 12 12 A-R-MUTE 10 10 SURROUND-L-MUTE 8 8 SURROUND-R-MUTE 6 6 CENTER-MUTE 14 14 A-L-MUTE 4 4 SUB WOOFER-MUTE 16 16 A-MUTE2 3 3 A-MUTE 2 2 M-MUTE MUTE-ON 1 7 2 6 MUTE-ON IC7301 Q7307 Q7308 (AMP) FRONT(L)- OUT FRONT(R)- OUT Q7302 JK7101 Q7301 MUTE-ON 1 7 2 6 Q7351 Q7352 MUTE-ON IC7401 Q7403 Q7404 (AMP) SURROUND(L) -OUT SURROUND(R) -OUT Q7402 Q7401 MUTE-ON 1 7 2 6 MUTE-ON IC7501 Q7503 Q7504 (AMP) CENTER OUT SUB WOOFER OUT Q7502 Q7501 MUTE-ON 1 7 2 6 DSD FILTER (X8 DF) 51 50 49 48 47 46 37 38 39 40 41 42 43 44 45 2 3 SYSTEM CLOCK 33 4 ICS10 1 2 4 ICS11 1 2 4 ICS07 2 1 4 ICS21 1 2 4 SD0/SPDIF SACD CLK33M/36M TO SACD BLOCK DIAGRAM TO SACD BLOCK DIAGRAM TO SACD BLOCK DIAGRAM TO SYSTEM CONTROL /SERVO BLOCK DIAGRAM TO VIDEO BLOCK DIAGRAM TO SYSTEM CONTROL /SERVO BLOCK DIAGRAM TO DIGITAL SIGNAL PROCESS BLOCK DIAGRAM 36 SACD-RESET TO DIGITAL SIGNAL PROCESS BLOCK DIAGRAM A-MUTE M-MUTE A-L-MUTE A-R-MUTE SURROUND-L-MUTE SURROUND-R-MUTE CENTER-MUTE SUB WOOFER-MUTE DSD I/F Q7451 Q7452 Q7551 Q7552 (AND GATE) (AND GATE) (AND GATE) (AND GATE) Q1203 19 19 AUDIO(L)-MUTE WF4 WF6 WF5 6 AUDIO(L)-MUTE SD7 AUDIO SIGNAL DATA(AUDIO) SIGNAL www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 29 DVD-1920/756 SACD Block Diagram ICS01 (SACD MULTI CHANNEL SIGNAL PROCESS) ICS12 (SD-RAM) 60 63 65 68 70 73 75 64 66 69 71 74 76 STREAM MANAGER XSHD XSRQ SDCK SDEF SACD-RESET SACD-RESET WCK ADDRESS (0-11) DATA (0-7) SACD-READY SACD-LATCH SACD-DATA XSRQ SDEF SACD-RESET PSP-WCK SACD-READY SACD-LATCH SACD-DATA TO DIGITAL SIGNAL PROCESS BLOCK DIAGRAM TO DIGITAL SIGNAL PROCESS BLOCK DIAGRAM TO AUDIO BLOCK DIAGRAM TO AUDIO BLOCK DIAGRAM TO AUDIO BLOCK DIAGRAM SDCK DSD FADE DSD SIGNAL PROCESS DSD OUTPUT I/F ADDRESS BUS DATA BUS DST DECODER 6 2 7 123 9 31 168 XSAK 167 166 164 165 173 174 175 176 169 170 171 172 11 PCM-SCLK 148,149,151,152, 154-157,159-162 131-134, 136-139 19-24, 27-32 2,3,5,6, 8,9,11,12 55 56 ICS13 1 2 1 2 4 ADAC-MD ADAC-MC ADAC-MD ADAC-MC 3 4 PCM-SCLK TO SYSTEM CONTROL/SERVO BLOCK DIAGRAM SURROUND-R-MUTE SURROUND-R-MUTE SURROUND-L-MUTE SURROUND-L-MUTE SUB WOOFER-MUTE SUB WOOFER-MUTE CENTER-MUTE CENTER-MUTE A-L-MUTE A-R-MUTE A-L-MUTE A-R-MUTE DSD-CLK DSD-XML DSD-XMR DSD-FL DSD-FR DSD-C DSD-SW DSD-LS DSD-RS (AND GATE) ICS08 4 (AND GATE) DVD MAIN CBA UNIT XSHD XSAK SD0/SPDIF SD1 SD2 SD3 SD5 SD4 SD6 SD7 DATA(AUDIO) SIGNAL SACD-RESET www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 30 DVD-1920/756 Power Supply Block Diagram IC1006 (SHUNT REGULATOR) REG AC1001 AC CORD F1001 1A 250V LINE FILTER L1001 D1001, D1002 D1004, D1005 Q1003 Q1001 2 4 7 3 4 IC1001 ERROR VOLTAGE DET T1001 11 12 13 15 14 16 17 18 SWITCHING SWITCHING CONTROL 1 2 6 BRIDGE RECTIFIER HOT HOT CIRCUIT. BE CAREFUL. D1003 RECTIFIER D1030 RECTIFIER D1016 RECTIFIER Q1016 Q1005 Q1011 Q1015 Q1002 CN1001 Q1004 -FL EV+5V F1 P-ON+10V EV+3.3V P-ON+5V +1.2V REG. IC1002 D1006 SCHOTTKY BARRIER SCHOTTKY BARRIER D1008 F2 AV CBA TO CN401 Q1008 LATCH Q1014 TO SYSTEM CONTROL/SERVO BLOCK DIAGRAM INV-POWCON Q1020 4,5 EV+1.2V 6,7,8 EV+3.3V 11,12 EV+10V 10 P-ON+5V 1,2,3,9 P-ON+3.3V 20 PWRCON Q1021 A V F CAUTION ! Fixed voltage (or Auto voltage selectable) power supply circuit is used in this unit. If Main Fuse (F1001) is blown , check to see that all components in the power supply circuit are not defective before you connect the AC plug to the AC power supply. Otherwise it may cause some components in the power supply circuit to fail. NOTE: The voltage for parts in hot circuit is measured using hot GND as a common terminal. "Ce symbole reprèsente un fusible à fusion rapide." CAUTION ! For continued protection against fire hazard, replace only with the same type fuse. ATTENTION : Pour une protection continue les risqes d'Incele n'utiliser que des fusible de même type. Risk of fire-replace fuse as marked. "This symbol means fast operating fuse." A V F www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 31 DVD-1920/756 SCHEMATIC DIAGRAMS / CBA’S AND TEST POINTS Standard Notes WARNING Many electrical and mechanical parts in this chassis have special characteristics. These characteristics often pass unnoticed and the protection afforded by them cannot necessarily be obtained by using replacement components rated for higher voltage, wattage, etc. Replacement parts that have these spe- cial safety characteristics are identified in this manual and its supplements; electrical components having such features are identified by the mark " ! " in the schematic diagram and the parts list. Before replacing any of these components, read the parts list in this manual carefully. The use of substitute replacement parts that do not have the same safety characteristics as specified in the parts list may create shock, fire, or other hazards. Notes: 1. Do not use the part number shown on these draw- ings for ordering. The correct part number is shown in the parts list, and may be slightly different or amended since these drawings were prepared. 2. All resistance values are indicated in ohms (K=103, M=106). 3. Resistor wattages are 1/4W or 1/6W unless other- wise specified. 4. All capacitance values are indicated in µF (P=10-6 µF). 5. All voltages are DC voltages unless otherwise specified. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 32 DVD-1920/756 LIST OF CAUTION, NOTES, AND SYMBOLS USED IN THE SCHEMATIC DIAGRAMS ON THE FOLLOWING PAGES: 1. CAUTION: FOR CONTINUED PROTECTION AGAINST FIRE HAZARD, REPLACE ONLY WITH THE SAME TYPE FUSE. ATTENTION: POUR UNE PROTECTION CONTINUE LES RISQES D'INCELE N'UTILISER QUE DES FUSIBLE DE MÊME TYPE. RISK OF FIRE-REPLACE FUSE AS MARKED. 2. CAUTION: Fixed Voltage (or Auto voltage selectable) power supply circuit is used in this unit. If Main Fuse (F1001) is blown, first check to see that all components in the power supply circuit are not defective before you connect the AC plug to the AC power supply. Otherwise it may cause some components in the power supply circuit to fail. 3. Note: (1) Do not use the part number shown on the drawings for ordering. The correct part number is shown in the parts list, and may be slightly different or amended since the drawings were prepared. (2) To maintain original function and reliability of repaired units, use only original replacement parts which are listed with their part numbers in the parts list section of the service manual. 4. Voltage indications for PLAY and STOP mode on the schematics are as shown below: 5. How to read converged lines 6. Test Point Information A V F This symbol means fast operating fuse. Ce symbole represente un fusible a fusion rapide. 2 3 1 5.0 (2.5) 5.0 The same voltage for both PLAY & STOP modes Indicates that the voltage is not consistent here. PLAY mode STOP mode (Unit: Volt) 1-D3 Distinction Area Line Number (1 to 3 digits) Examples: 1. "1-D3" means that line number "1" goes to the line number "1" of the area "D3". 2. "1-B1" means that line number "1" goes to the line number "1" of the area "B1". 3 2 1 A B C D 1-B1 1-D3 AREA D3 AREA B1 : Indicates a test point with a jumper wire across a hole in the PCB. : Used to indicate a test point with a component lead on foil side. : Used to indicate a test point with no test pin. : Used to indicate a test point with a test pin. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 33 DVD-1920/756 DVD Main 1/7 Schematic Diagram w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 34 DVD-1920/756 DVD Main 2/7 Schematic Diagram w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 35 DVD-1920/756 IC101 Voltage Chart PIN.NO PLAY STOP PIN.NO PLAY STOP PIN.NO PLAY STOP PIN.NO PLAY 1 3.4 3.4 33 ~ ~ 65 ----- ----- 97 0 2 0 0 34 0 0 66 3.4 3.4 98 0 3 3.5 3.5 35 3.5 3.5 67 3.4 3.4 99 0 4 3.5 3.5 36 ~ ~ 68 0 0 100 0 5 0 0 37 ~ ~ 69 3.5 3.5 101 0 6 ----- ----- 38 ~ ~ 70 3.6 3.4 102 3.5 7 3.3 0.8 39 ~ ~ 71 3.2 3.2 103 0.9 8 3.5 3.5 40 ~ ~ 72 3.5 0.1 104 0 9 0 0 41 ~ ~ 73 3.5 3.5 105 2.4 10 ----- ----- 42 ~ ~ 74 3.4 3.4 106 1.9 11 ----- ----- 43 ~ ~ 75 3.4 3.4 107 0.4 12 ----- ----- 44 0 0 76 3.2 3.2 108 0 13 0.1 0.1 45 1.3 1.3 77 3.5 3.5 109 1.7 14 ----- ----- 46 ~ ~ 78 3.4 3.4 110 3.5 15 3.4 3.4 47 ~ ~ 79 ----- ----- 111 ----- 16 0 0 48 ~ ~ 80 3.2 3.2 112 ----- 17 3.5 3.5 49 ~ ~ 81 3.5 3.5 113 1.9 18 ~ ~ 50 ~ ~ 82 0 0 114 1.9 19 2.4 2.8 51 ~ ~ 83 1.3 1.3 115 1.7 20 2.4 2.8 52 0 0 84 3.3 3.3 116 1.7 21 0 0 53 3.5 3.5 85 1.4 2.7 117 1.7 22 1.3 1.3 54 ~ ~ 86 0.1 0.1 118 1.7 23 ~ ~ 55 3.4 3.4 87 0 0 119 3.5 24 ~ ~ 56 ~ ~ 88 3.4 0 120 2.0 25 ~ ~ 57 ~ ~ 89 3.4 3.5 121 1.5 26 ~ ~ 58 ~ ~ 90 2.3 1.8 122 0 27 ~ ~ 59 ~ ~ 91 1.7 1.8 123 0.3 28 ~ ~ 60 ~ ~ 92 0 0 124 1.1 29 ~ ~ 61 ~ ~ 93 3.5 3.5 125 0.3 30 ~ ~ 62 ~ ~ 94 0 0 126 0.1 31 ~ ~ 63 ~ ~ 95 0 0 127 2.3 32 ~ ~ 64 ~ ~ 96 0 0 128 1.7 STOP PIN.NO PLAY STOP PIN.NO PLAY STOP PIN.NO PLAY STOP PIN.NO PLAY STOP 0 129 2.3 2.3 161 0 0 193 3.2 3.2 225 1.9 1.9 0 130 2.3 2.3 162 1.7 1.7 194 3.2 3.2 226 0 0 0 131 2.3 2.3 163 1.7 1.7 195 1.7 1.7 227 3.2 3.2 0 132 2.4 2.3 164 0 0 196 0 0 228 3.3 3.3 0 133 2.4 2.4 165 1.3 1.3 197 3.5 3.5 229 3.0 3.0 3.5 134 2.4 2.4 166 3.2 3.2 198 ~ ~ 230 ~ ~ 0.8 135 2.3 2.3 167 3.2 3.2 199 ~ ~ 231 1.6 1.6 0 136 2.3 2.3 168 0 0 200 ~ ~ 232 ~ ~ 2.4 137 2.3 2.3 169 0 0 201 ~ ~ 233 0 0 1.9 138 2.3 2.3 170 0 0 202 ~ ~ 234 1.3 1.3 0.3 139 2.1 1.7 171 0 0 203 ~ ~ 235 1.4 1.4 0 140 1.7 1.7 172 0 0 204 3.5 3.5 236 ~ ~ 1.7 141 1.7 1.7 173 3.2 3.2 205 0 0 237 ~ ~ 3.5 142 1.7 1.7 174 0 0 206 ~ ~ 238 0 0 ----- 143 0 0 175 3.5 3.5 207 ~ ~ 239 3.4 3.4 ----- 144 1.7 1.7 176 1.3 1.3 208 ~ ~ 240 ~ ~ 1.9 145 1.7 1.7 177 1.3 1.3 209 ~ ~ 241 ~ ~ 1.9 146 3.5 3.5 178 1.3 1.3 210 ~ ~ 242 ~ ~ 1.7 147 ----- ----- 179 1.5 1.5 211 ~ ~ 243 ~ ~ 1.7 148 ----- ----- 180 1.0 1.0 212 ~ ~ 244 ~ ~ 1.7 149 ----- ----- 181 1.0 1.0 213 ~ ~ 245 ~ ~ 1.7 150 3.5 3.5 182 1.0 1.0 214 3.5 3.5 246 ~ ~ 3.5 151 2.2 2.2 183 1.0 1.0 215 0 0 247 ~ ~ 2.0 152 1.4 1.3 184 3.5 3.5 216 ~ ~ 248 0 0 1.5 153 1.4 1.3 185 0 0 217 ~ ~ 249 3.4 3.4 0 154 2.2 2.2 186 1.5 1.5 218 1.3 1.3 250 ----- ----- 0.1 155 0 0 187 3.3 3.3 219 2.4 2.1 251 ----- ----- 0 156 0.6 0.6 188 3.3 3.3 220 2.4 2.1 252 3.4 3.4 0.1 157 0.9 0.9 189 0 0 221 3.3 3.3 253 2.8 2.8 0.1 158 3.5 3.5 190 1.6 1.6 222 0 0 254 3.3 3.3 2.3 159 0 0 191 3.3 3.3 223 1.6 1.6 255 3.4 3.4 1.7 160 3.5 3.5 192 3.2 3.2 224 3.5 3.5 256 3.4 3.4 ~ : Voltage is not consistent ----- : Not used Unit : Volts w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 36 DVD-1920/756 DVD Main 3/7 Schematic Diagram w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 37 DVD-1920/756 DVD Main 4/7 Schematic Diagram w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 38 DVD-1920/756 DVD Main 5/7 Schematic Diagram w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 39 DVD-1920/756 DVD Main 6/7 Schematic Diagram w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 40 DVD-1920/756 DVD Main 7/7 Schematic Diagram w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 41 DVD-1920/756 AV 1/3 Schematic Diagram CAUTION ! Fixed voltage (or Auto voltage selectable) power supply circuit is used in this unit. If Main Fuse (F1001) is blown , check to see that all components in the power supply circuit are not defective before you connect the AC plug to the AC power supply. Otherwise it may cause some components in the power supply circuit to fail. NOTE: The voltage for parts in hot circuit is measured using hot GND as a common terminal. "Ce symbole reprèsente un fusible à fusion rapide." CAUTION ! For continued protection against fire hazard, replace only with the same type fuse. ATTENTION : Pour une protection continue les risqes d'Incele n'utiliser que des fusible de même type. Risk of fire-replace fuse as marked. "This symbol means fast operating fuse." A V F w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 42 DVD-1920/756 AV 2/3 Schematic Diagram w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 43 DVD-1920/756 5G 4G 3G 2G 1G 7G 6G a d g c b e f f i i REPEAT TITLE GROUP VCR CHP REC SACD TRK A ALL B PSCAN DVD PM HDVCD A 7G 6G 5G 4G 3G 2G 1G a b c d e f g c d e f f g c d e f g c d e f g c d e f g c d e f g h i i a b a b a b a b a b FL2001 MATRIX CHART REPEAT TITLE GROUP VCR CHP REC SACD TRK ALL B PSCAN DVD P M HD V CD A A AV 3/3, Function & LED Schematic Diagram w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 44 DVD-1920/756 5.1ch Amp Schematic Diagram E E SCA w w w . x i a o y u 1 6 3 . c o m Q Q 3 7 6 3 1 5 1 5 0 9 9 2 8 9 4 2 9 8 T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 45 DVD-1920/756 WAVEFORMS WF6 WF1 WF3 WF4 WF5 WF2 NOTE: Input CD: 1kHz PLAY (WF4~WF6) DVD: POWER ON (STOP) MODE (WF1~WF3) Pin 18 of CN1601 Pin 8 of CN1601 C1402 PLUS LEAD Pin 13 of CN1601 Pin 15 of CN1601 Pin 10 of CN1601 20µs 0.1V 0.1V VIDEO-Y VIDEO-C VIDEO-C 0.1V 20µs VIDEO-CVBS VIDEO-CVBS 0.5V 20µs AUDIO(L) 1V 0.5ms AUDIO(R) 1V 0.5ms SPDIF 1V 0.1µs www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 46 DVD-1920/756 WIRING DIAGRAM CN201 CN301 TRAY-IN FG SENSOR EV+1.2V 4 EV+1.2V 5 EV+3.3V 7 EV+3.3V 8 P-ON+3.3V 9 P-ON+3.3V 3 P-ON+5V 10 EV+10V 11 EV+10V 12 GND 13 GND 14 GND 15 GND 16 GND 17 GND 18 GND 19 PWRCON 20 FP-CLK 21 FP-DIN 22 FP-STB 23 FP-DOUT 24 REMOTE 25 HDMI 26 CN401 CN1001 CN2001 CN2101 VIDEO-C 10 10 GND 9 9 VIDEO-Cr/Pr 4 4 VIDEO-Y(I) 3 3 GND 5 5 VIDEO-Cb/Pb 6 6 GND 7 7 VIDEO-Y(I/P) 8 8 CN601 AC CORD FRONT(R)- OUT FRONT(L)- OUT SURROUND(R)- OUT SURROUND(L)- OUT CENTER OUT SUB WOOFER OUT S-VIDEO OUT REMOCON -IN REMOCON -OUT EV+3.3V 6 5 6 8 9 10 4 3 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 7 KEY-6 1 3 K2 2 4 K1 3 5 KEY-2 4 6 KEY-3 5 7 CN1301 CN7101 CNS01 CN7102 GND 3 3 EV+3.3V 4 4 GND 1 1 GND 2 2 AUDIO+5V 5 5 AUDIO+10V 6 6 AUDIO+10V 7 7 A-MUTE 3 3 SUB WOOFER-MUTE 4 4 GND 1 1 M-MUTE 2 2 SUB WOOFER 5 5 CENTER-MUTE 6 6 CENTER 7 7 SURROUND-L-MUTE 10 10 SURROUND-L 11 11 SURROUND-R-MUTE 8 8 SURROUND-R 9 9 A-R-MUTE 12 12 FRONT-AUDIO-R 13 13 A-L-MUTE 14 14 FRONT-AUDIO-L 15 15 A-MUTE2 16 16 KEY-1 6 8 KEY-4 7 9 AUDIO(R) 15 15 AUDIO-GND 11 11 AUDIO-GND 12 12 AUDIO(L) 13 13 AUDIO(R)-MUTE 14 14 FS TS DETECTOR 7 9 11 2 3 6 5 M SLED MOTOR M SPINDLE MOTOR AUDIO+5V 16 16 AUDIO+5V 17 17 SPDIF 18 18 AUDIO(L)-MUTE 19 19 4 CN2002 CN2102 EV+5V 1 1 POWER-LED 2 2 STANDBY-LED 3 3 GND 4 4 KEY-2 5 5 K2 6 6 HDMI-LED 7 7 CN702 SP(+) 3 SP(-) 4 TRAY-IN 5 GND 6 SL(-) 7 SL(+) 8 FS(-) 3 TS(-) 4 GND(CD-PD) 5 GND(DVD-PD) 6 PD-MONI 7 DVD-LD 8 TS(+) 1 FS(+) 2 GND 11 F 12 VREF 13 E 14 B 15 C 16 GND(LD) 9 CD-LD 10 A 17 D 18 CD/DVD 19 P-ON+5V 20 FG-IN 1 P-ON+3.3V 2 2 GND 4 EV+3.3V(D) 6 RESET 1 SCLOCK 3 EXTRG0 5 SDATA 7 NU 8 GND 9TRCDATA1 10 NU 11 NU 12 NU 9 NU 13 NU LED CBA CN2102 is soldered directly to the PCB. AV CBA (CN1001 is soldered directly to the PCB.) CN1601 (CN1601 is soldered directly to the PCB.) (NO CONNECTION ) DVD MAIN CBA UNIT DRIVE CBA FG CBA PICK UP UNIT 5.1CH AMP CBA FUNCTION CBA CN2101 is soldered directly to the PCB. VIDEO-Y OUT VIDEO-Cb/Pb OUT VIDEO-Cr/Pr OUT DVD MECHANISM VIDEO OUT (COMPOSITE) AUDIO(L)- OUT AUDIO(R)- OUT DIGITAL AUDIO OUT (COAXIAL) DIGITAL AUDIO OUT (OPTICAL) HDMI-CONNECTOR P-ON+3.3V 2 2 P-ON+3.3V 1 1 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 47 DVD-1920/756 LEAD IDENTIFICATIONS 28 15 14 1 E C B E C B A K C E K A R 8 5 4 1 G D S 2SK3563 1 2 3 1 2 3 24 13 12 1 1: R 2: A 3: K 1: A 2: K 3: E 4: C E C B 2SD2144S B C E KTD882 Note: A: Anode K: Cathode E: Emitter C: Collector B: Base R: Reference G: Gate D: Drain S: Source NJM4580M-TE1 RC4580IP MM1636XWRE CXA1511M-T4 PT6313-S-TP(L) SC16313G 2SA1015-Y(TE2 F T) 2SA1015-Y(TPE2) 2SC2120-Y(TE2 F T) 2SC2120-Y(TPE2) 2SC2236-Y-TPE6 C KTA1266(Y) KTA1266-Y-AT/P KTC3203(Y) KTC3203-Y-AT/P KTC3205(Y) KTC3205-Y-AT/P 2SA966-Y(TE6 F M) 2SA966(Y) KTC3198(Y) 2SC1815-GR(TE2 F T) 2SC1815-GR(TPE2) KTA1267(Y) KTA1267Y-AT/P KTC3199(GR) KTC3199-GR-AT/P KTC3198-Y-AT/P BN1L3Z(P) KRA105M-AT/P KRA110M-AT/P KTA1273(Y) EL817B EL817C LTV-817B-F LTV-817C-F PS2561A-1(W) FAN431AZXA KIA431-AT GP1FA513TZ LD1117SC-R 1: GND 2: Vout 3: Vin MM1622XJBEG www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 48 DVD-1920/756 EXPLODED VIEWS Cabinet DVD Main CBA Unit 5.1ch Amp CBA 2L106 2L071 2L041 2L043 2L041 2L021 2B34 2L021 2L105 2L105 2L021 2L021 1B1 2L051 2B2 2B4 2B3 2L051 2L102 A' A 2L102 2L023 2L023 2L052 2L052 A11 A1X A13 A12 A13 A15 A17 A2 A21 A16 2L011 2L101 2L011 2L011 2L109 2L108 2B6 2L011 2L011 AV CBA 2L106 2L107 JK1401 JK1404 JK1202 IC1204 LED CBA AC1001 F1001 2L041 2L041 JK3501 See Electrical Parts List for parts with this mark. Some Ref. Numbers are not in sequence. Function CBA www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 49 DVD-1920/756 Packing X10 X2 X4 S2 S2 S4 Unit S1 X12 X1 X5 A30 A22 A30 X21 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 50 DVD-1920/756 PARTS LIST PRODUCT SAFETY NOTE: Products marked with a ! have special characteristics important to safety. Before replacing any of these components, read care- fully the product safety notice in this service manual. Don't degrade the safety of the product through improper servicing. NOTE: Parts that are not assigned part numbers (---------) are not available. Comparison Chart of Models and Marks Model Mark DVD1920BKE3 A DVD1920SRE3 B DVD756SRE3 C Ref. No. Mark Description Funai Parts No. DENON Parts No. Qty New MECHANICAL PARTS A1X A FRONT ASSEMBLY 1VM220754 00D 9H2 6000 642 1 * A1X B FRONT ASSEMBLY 1VM220755 00D 9H2 6000 643 1 * A1X C FRONT ASSEMBLY 1VM220760 00D 9H2 6000 644 1 * A2 A TRAY PANEL ASSEMBLY 1VM422186 00D 9H2 6000 645 1 * A2 B,C TRAY PANEL ASSEMBLY 1VM422188 00D 9H2 6000 646 1 * A11 INSULATOR ASSEMBLY (R) 1VM420732 00D 9H2 6000 566 1 A12 INSULATOR ASSEMBLY (L) 1VM420733 00D 9H2 6000 567 1 A13 FOOT 0VM406940A 00D 9H2 6000 323 2 A15 CHASSIS 1VM120073 00D 9H2 6000 611 1 A16 A TOP COVER(BLACK) 1VM120074 00D 9H2 6000 612 1 A16 B,C TOP COVER(SILVER) 1VM320865 00D 9H2 6000 613 1 A17 A,B REAR PANEL 1VM220781 00D 9H2 6000 647 1 * A17 C REAR PANEL 1VM220889 00D 9H2 6000 648 1 * A21 LABEL SERIAL NO. ---------- - 1 A22 A BAR CODE LABEL ---------- - 1 A22 B BAR CODE LABEL ---------- - 1 A22 C BAR CODE LABEL ---------- - 1 A30 A CONTROL LABEL ---------- - 2 A30 B CONTROL LABEL ---------- - 2 A30 C CONTROL LABEL ---------- - 2 1B1 DVD MECHA N79F1JVM 00D 9H2 6000 649 1 * 2B2 POWER PCB HOLDER 0VM306801 - 1 * 2B3 MAIN PCB HOLDER 1VM320650 - 1 * 2B4 LOADER BASE 0VM101367E 00D 9H2 6000 616 1 2B6 JACK PCB HOLDER 0VM101376 - 1 * 2B16 M-PCB PLATE EARTH 1VM421132 - 2 * 2B34 CUSHION SPACER 1VM422273 - 1 * 2L011 A SCREW C-TIGHT M3X5 BIND HEAD + GBKC3050 00D 9H2 6000 257 5 2L011 B,C SCREW C-TIGHT M3X5 BIND HEAD + GBCC3050 00D 9H2 6000 301 5 2L021 SCREW P-TIGHT 3X12 BIND HEAD+ GBMP3120 00D 9H2 6000 517 4 2L023 SCREW C-TIGHT M3X6 BIND HEAD GBMC3060 00D 9H2 6000 303 2 2L041 SCREW B-TIGHT M3X8 BIND HEAD + GBKB3080 00D 9H2 6000 304 8 2L043 SCREW C-TIGHT M3X5 BIND HEAD + GBKC3050 00D 9H2 6000 257 1 2L051 C-TITE SCREW M3*8 BIND GBMC3080 00D 9H2 6000 518 2 2L052 P-TIGHT SCREW 3X8 BIND + GBMP3080 00D 9H2 6000 240 6 2L071 SCREW C-TIGHT M3X5 BIND HEAD + GBKC3050 00D 9H2 6000 301 1 2L101 SCREW C-TIGHT M3X6 BIND HEAD GBMC3060 00D 9H2 6000 303 1 2L102 SCREW C-TIGHT M3X6 BIND HEAD GBMC3060 00D 9H2 6000 303 4 2L105 P-TIGHT SCREW 3X8 BIND + GBMP3080 00D 9H2 6000 240 3 2L106 SCREW C-TIGHT M3X6 BIND HEAD GBMC3060 00D 9H2 6000 303 4 2L107 P-TIGHT SCREW 3X8 BIND + GBMP3080 00D 9H2 6000 240 1 2L108 SCREW C-TIGHT M3X6 BIND HEAD GBMC3060 00D 9H2 6000 303 2 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 51 DVD-1920/756 2L109 P-TIGHT SCREW 3X8 BIND + GBMP3080 00D 9H2 6000 240 1 S1 A GIFT BOX CARTON 1VM321125 00D 9H2 6000 650 1 * S1 B GIFT BOX CARTON 1VM321136 00D 9H2 6000 651 1 * S1 C GIFT BOX CARTON 1VM321186 00D 9H2 6000 652 1 * S2 STYROFOAM 0VM101298B 00D 9H2 6000 619 1 S4 SET BAG 0DM400731A 00D 9H2 6000 620 1 X1 A,B REMOTE CONTROL UNIT NA834UD 00D 9H2 6000 653 1 * X1 C REMOTE CONTROL UNIT NA835UD 00D 9H2 6000 654 1 * X2 DRY BATTERY R6P/2S XB0M451T0001 - 2 X2 DRY BATTERY ES-GR6M-C XB0M571GLP01 - 2 X4 ACCESSORY BAG 0VM416059 - 1 X5 AV CORD TSCKA-Y/RW100 WPZ0102TM015 00D 9H2 6000 226 1 X5 AV CORD RCA(M*2)TO RCA(M*2) WPZ0102LTE01 - 1 X5 AV CORD DC2FN020001 WPZ0102CAB01 - 1 ! X10 A,B OWNERS MANUAL 1VMN20946 00D 9H2 6000 655 1 * ! X10 C OWNERS MANUAL 1VMN21032 00D 9H2 6000 656 1 * X12 SERVICE CENTER SHEET 1VM422133 - 1 X21 WARRANTY SHEET 0VM305871B 00D 9H2 6000 643 1 DVD MAIN CBA UNIT N79D2JUP 00D 9H2 6000 657 1 * AV ASSEMBLY 1VSA12089 00D 9H2 6000 658 1 * Consists of the following: AV CBA ---------- - FUNCTION CBA ---------- - LED CBA ---------- - 5.1ch Amp CBA 1VSA12380 00D 9H2 6000 673 1 * Ref. No. Mark Description Funai Parts No. DENON Parts No. Qty New www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com
