Important Safety Notice . . . . . . . . . . . . . . . . . . . 2 Technical Data. . . . . . . . . . . . . . . . . . . . . . . . . . . 3 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 OSD Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . 5 OSD lock & service modes. . . . . . . . . . . . . . . . . 6 Warning and Notes . . . . . . . . . . . . . . . . . . . . . . . 7 DDC DATA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 DDC Instructions. . . . . . . . . . . . . . . . . . . . . . . . . 9~12 Electrical Adjustments . . . . . . . . . . . . . . . . . . . . 13~15 Purity and Static convergence Adjustments . . 16 Mechanical Instructions . . . . . . . . . . . . . . . . . . . 17 Safety Test Requirements (Hipot & Ground) . . 18 Wiring Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . 19 Block Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . 20 Terminal(A1) Schematic Diagram & PCB (A1)...21 Video(A2) Schematic Diagram & PCB (A2).......22 Deflection(B) Schematic Diagram....................23 Waveforms (A, B, C)........................................24 PCB (B, C)..................................................... 25 Power Board(Diagram C) & Control Panel ........26 Driver(D) Schematic Diagram & PCB (D)..........27 Sensor(E) Schematic Diagram & PCB (E).........28 Repair Tips ....................................................29 Exploded View................................................30 Recommended Parts List.................................31 Spare Parts List...............................................32~39 Repair flow chart..............................................40~47 General Product Specification..........................48~78 Description Description Page Page Table of Contents 19" Auto scan Colour Monitor DDC/Power saving/TCO CHASSIS: CM25 Horizontal frequencies 30 - 111kHz Service Service Service Published by BCU Monitors Printed in Taiwan Copyright reserved Subject to modification Sep. 15 2000 © GB 3138 106 10118 109P20/00(PHILIPS) 109P2 CM25 GSIII REFER TO BACK COVER FOR IMPORTANT SAFETY GUIDELINES CAUTION: USE A SEPARATE ISOLATION TRANSFORMER FOR THIS UNIT WHEN SERVICING. SAFETY NOTICE ANY PERSON ATTEMPTING TO SERVICE THIS CHASSIS MUST FAMILIARIZE HIMSELF WITH THE CHASSIS AND BE AWARE OF THE NECESSARY SAFETY PRECAUTIONS TO BE USED WHEN SERVICING ELECTRONIC EQUIPMENT CONTAINING HIGH VOLTAGES. Important Safety Notice Proper service and repair is important to the safe, reliable operation of all Philips Company** Equipment. The service procedures recommended by Philips and described in this service manual are effective methods of performing service operations. Some of these service operations require the use of tools specially designed for the purpose. The special tools should be used when and as recommended. It is important to note that this manual contains various CAUTIONS and NOTICES which should be carefully Read in order to minimize the risk of personal injury to service personnel. The possibility exists that improper Service methods may damage the equipment. It also is important to understand that these CAUTIONS and NOTICES ARE NOT EXHAUSTIVE. Philips could not possibly know, evaluate and advise the service trade of all conceivable ways in which service might be done or of the possible hazardous consequences of each way. Consequently, Philips has not undertaken any such broad evaluation. Accordingly, a servicer who uses a service procedure or tool which is not recommended by Philips must first satisfy himself thoroughly that Neither his safety nor the safe operation of the equipment will be jeopardized by the service method selected. * * Hereafter throughout this manual, Philips Company will be referred to as Philips. Critical components having special safety characteristics are identified with a by the Ref. No. in the parts list and enclosed within a broken line* (where several critical components are grouped in one area) along with the safety symbol on the schematics or exploded views. Use of substitute replacement parts which do not have the same specified safety characteristics may create shock, fire, or other hazards. Under no circumstances should the original design be modified or altered without written permission from Philips. Philips assumes no liability, express or implied, arising out of any unauthorized modification Of design. Servicer assumes all liability. WARNING * Broken Line FOR PRODUCTS CONTAINING LASER : Invisible laser radiation when open. AVOID DIRECT EXPOSURE TO BEAM. Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure. The use of optical instruments with this product will increase eye hazard. DANGER- CAUTION- CAUTION- TO ENSURE THE CONTINUED RELIABILITY OF THIS PRODUCT, USE ONLY ORIGINAL MANUFACTURER'S REPLACEMENT PARTS, WHICH ARE LISTED WITH THEIR PART NUMBERS IN THE PARTS LIST SECTION OF THIS SERVICE MANUAL. 2 109P2 GS3 CM25 � Go to cover page Forward Back 3 Technical Data Technical Specification* CRT Size and deflection :19 inch/46cm,90 defection angle Dot pitch/Grille pitch : 0.24mm Tube type : Phosphor : P22 Recommended display area : 14.0"x10.4"/355 x 265 mm Maximum display area : 14.4"x10.8"/365 x 274 mm Scanning Horizontal scanning : 30 - 111 KHz Vertical : 50 - 160 Hz Video Video dot rate : 261 Mhz Input impedance -Video : 75 Ohm - Sync : 2.2 kOhm Input signal levels : 0.7Vpp Separate sync Sync polarities : Positive and negative O : Composite sync Aperture grille, flat, high contrast, anti-glare, anti-static, anti reflection, light transmission 41% scanning Sync input signal Pin assignment : The 15-pin D-sub connector(male) of the signal cable (IBM systems) : Assignment Assignment Pin No. Pin No. Identification output - Connected to pin 10 Identification output - Connected to pin 10 Blue video input 2 7 6 8 4 5 3 1 9 12 11 14 13 15 10 Red video ground Blue video ground Green video ground Ground No pin Logic ground Data clock line(SCL) V.Sync(VCLK for DDC) H.Sync /H+V Serial data line(SDA) Green video input Red video input 1 10 6 11 15 5 If you have VESA's DPMS compliance display card or software installed in your PC,the monitor can automaticlly reduce its power consumption when not in use. And if an input from a keyboard, mouse or other input devices is detected, the monitor will automatically "wake up". The following table shows the power consumption and signalling of this automatic power saving features : Automatic Power Saving Power Management Definition Active Amber Yellow Green Yellow Blanked Blanked Blanked < 3 W 97 % 95 % 95 % 0 % < 6 W < 6 W Typical 120W Suspend ON OFF No No No No Yes Yes Yes Yes Stand-by V-SYNC POWER SAVING( % ) POWER USED LED COLOR H-SYNC VIDEO VESA’s mode This monitor is Energy Star compliant .As an ENERGY STAR Partner, PHILIPS has determined that this product meets the ENERGY STAR guidelines for energy efficiency. White Color Temperature Chromaticity CIE coordinates: at 9300 k x = 0.283 y = 0.297 6500 k x = 0.313 y = 0.329 5500 k x = 0.332 y = 0.347 Physical Specifications Dimensions : 456x476x437mm(including base) 456x416x437mm(excluding base) weight : 23.5 Kg Power supply : 90 - 264 VAC, 50/60HZ Operating condition Temperature : 0 C - 35 C Relative Humidety : 10 % - 90 % Storage condition Temperature : - 25 C - 60 C Relative Humidity : 5 % - 95 % o o o O O O O 109P2 GS3 CM25 � Go to cover page Forward Back 4 109P2 GS3 CM25 Go to cover page Forward Back Front View and Back View Front View Front View Power button switches your monitor on. OK button which when pressed will take you to the OSD controls Contrast hotkey. When the UP arrow is pressed, the adjustment controls for the CONTRAST will show up. UP and DOWN buttons are used when adjusting the OSD of your monitor Brightness hotkey. When both the LEFT and RIGHT arrows are pressed at the same time, then the adjustment controls for BRIGHTNESS will show up. LEFT and RIGHT buttons, like the UP and DOWN buttons, are also used in adjusting the OSD of your monitor. By pressing both the UP and OK buttons, you can easily access the Input Signals A and/or B. 1. D-Sub Port - Attach the D-Sub connector that comes with your monitor here. Other end connects to your PC. 2. Power in - Attach power cable here. 3. USB Port - Attach your USB Upstream cable here. Connect the other end to your USB hub or your PC's USB connector. 4. BNC Connectors - Attach the connectors here to get the best video performance from your monitor 5 109PB2 GS3 CM25 Go to cover page Forward Back OSD Adjustment The OSD Tree On the front controls of your monitor, once you press the button, the OSD Main Controls window will pop up and you can now start making adjustment to your monitor's various features. Use the or the keys to make your adjustments within. Brightness 1. Press the or button on the monitor. The BRIGHTNESS window appears. To adjust your screen's brightness, follow the steps below. Brightness is the overall intensity of the light coming from the screen. A 50% brightness is recommended. Contrast 1. Press the or button on the monitor. The BRIGHTNESS window appears. To adjust your screen's contrast, follow the steps below. Contrast is the difference between the light and dark areas on the screen. A 100% contrast is recommended. 2. Press the or button to adjust the brightness. 3. When the brightness is adjusted to the level desired, stop pressing the or button and after three seconds the BRIGHTNESS window will disappear with the new adjustment saved. 2. Press the or button to adjust the brightness. 3. When the brightness is adjusted to the level desired, stop pressing the or button and after three seconds the BRIGHTNESS window will disappear with the new adjustment saved. 2. Press the or button to adjust the brightness. 3. When the brightness is adjusted to the level desired, stop pressing the or button and after three seconds the BRIGHTNESS window will disappear with the new adjustment saved. 2. Press the or button to adjust the brightness. 3. When the brightness is adjusted to the level desired, stop pressing the or button and after three seconds the BRIGHTNESS window will disappear with the new adjustment saved. 2. Press the or button to adjust the brightness. 3. When the brightness is adjusted to the level desired, stop pressing the or button and after three seconds the BRIGHTNESS window will disappear with the new adjustment saved. 2. Press the or button to adjust the brightness. 3. When the brightness is adjusted to the level desired, stop pressing the or button and after three seconds the BRIGHTNESS window will disappear with the new adjustment saved. 2. Press the or button to adjust the brightness. 3. When the brightness is adjusted to the level desired, stop pressing the or button and after three seconds the BRIGHTNESS window will disappear with the new adjustment saved. 2. Press the or button to adjust the brightness. 3. When the brightness is adjusted to the level desired, stop pressing the or button and after three seconds the BRIGHTNESS window will disappear with the new adjustment saved. Below is an overall view of the structure of the OSD. You can use this as reference when you want to later on work your way around the different adjustments. 6 109P2 GS3 CM25 Go to cover page Forward Back OSD Lock Function & Service Mode To unlock (enable) OSD function: - Press OSD button " " for over 10 seconds again to unlock the OSD function. Release it, then OSD comes on the screen as below. To lock (disable) OSD function: - Press OSD button " " for over 15 seconds to lock the OSD function. Release it, then OSD comes on the screen as below. ATTENTION CONTROL MENU IS LOCKED Disable/Enable all the WARNING SIGNAL NO SIGNAL INPUT To enable all the WARNING SIGNAL : - After disconnect the Interface cable of the monitor, then Monitor is powered ON. - If it is successful, the signal " " comes on the screen again later. Access Service mode (burn in mode) : Access Service Mode & Burn in mode Firstly, get into Factory Adjustment Mode. Push LEFT & RIGHT buttons at the same time for over 15 seconds and release them. The factory message appears at the bottom of the main OSD menu. (for example : 109P V3.08 000601; 00105 is M.T.B.F. in HOUR unit) SERVICE MODE SERIAL NO: TY 123456 HOURS : 00021 FACTORY VER 1.01 990706 109P V3.08 000601 00105 NO SIGNAL INPUT To disable all the WARNING SIGNAL : - Disconnect the Interface cable of the monitor (Monitor is ON.). - Press OSD button " " for over 15 seconds to disable all the WARNING SIGNAL. Then release the "OSD" button. - If it is successful, then the signal " "disappeared to enter power saving-off mode. - Disconnect the Interface cable of the monitor. - Push LEFT & RIGHT buttons at the same time, then power ON. - If it is successful, the signal " " comes on the screen later. (Background is white.). - Reconnect the interface cable to PC, then the "burn in MODE" Disappear. Exit "burn in MODE" : 7 109P2 GS3 CM25 Warning and Notes Fig.1 V Warnings 1 2 0 V 3 ESD 4 5 6 7 8 9 10. 11. . Safety regulations require that the unit should be returned in its original condition and that components identical to the original components are used. The safety components are indicated by the symbol . . In order to prevent damage to ICs and transistors, all high-voltage flash-overs must be avoided. In order to prevent damage to the picture tube, the method shown in Fig. 1 should be used to discharge the picture tube. Use a high-voltage probe and a multimeter (position DC-V). Discharge until the meter reading is (after approximately 30 seconds). . All ICs and many other semiconductors are sensitive to electrostatic discharges (ESD). Careless handling during repair can drastically shorten their life. Make sure that during repair you are connected by a pulse band with resistance to the same potential as the ground of the unit. Keep components and tools also at this same potential. . When repairing a unit, always connect it to the AC Power voltage via an isolating transformer. . Be careful when taking measurements in the high-voltage section and on the picture tube panel. . It is recommended that saferty goggles be worn when replacing the picture tube. . When making adjustments,use plastic rather than metal tools. This will prevent any short-circuit or the danger of a circuit becoming unstable. . Never replace modules or other components while the unit is switched on. . Together with the defleciton unit, the picture tube is used as an integrated unit. Adjustment of this unit during repair is not recommended. After repair, the wiring should be fastened in place with the cable clamps. All units that are returned for service or repair must pass the original manufactures safety tests. Notes . The direct voltages and waveforms are average voltages. They have been measured using the Service test software and under the following conditions : - Mode : 640 * 480 (31.5kHz / 60Hz) - Signal pattern : grey scale - Adjust brightness and contrast control for the mechanical mid-position (click position) . The picture tube panel has printed spark gaps. Each spark gap is connected between an electrode of the picture tube and the Aquadag coating. . The semiconductors indicated in the circuit diagram(s) and in the parts lists are completely interchangeable per position with the semiconductors in the unit, irrespective of the type indication on these semiconductors. 1 2 3 � Go to cover page Forward Back 8 109P2 GS3 CM25 DDC DATA * *********************************** EDID data for Mitsubishi CRT ************************************* 0:00 1: ff 2:ff 3:ff 4:ff 5:ff 6:ff 7:00 8: 41 9:0c 10:05 11:00 12:40 13:e2 14:01 15:00 16: 22 17:0a 18:01 19:02 20:6c 21:25 22:1b 23:a7 24: e9 25:7a 26:68 27:9f 28:56 29:47 30:99 31:26 32: 12 33:48 34:4c 35:fd 36:ff 37:80 38:d1 39:40 40: c1 41:40 42:a9 43:4f 44:81 45:99 46:81 47:80 48: 61 49:59 50:45 51:59 52:31 53:59 54:a6 55:59 56: 40 57:30 58:62 59:b0 60:32 61:40 62:40 63:c0 64: 13 65:00 66:63 67:09 68:11 69:00 70:00 71:18 72: 00 73:00 74:00 75:ff 76:00 77:20 78:54 79:59 80: 20 81:20 82:31 83:32 84:33 85:34 86:35 87:37 88: 0a 89:20 90:00 91:00 92:00 93:fc 94:00 95: 50 96: 48 97:49 98:4c 99:49 100:50 101:53 102:20 103:31 104: 30 105:39 106:50 107:32 108:00 109:00 110:00 111: fd 112: 00 113:32 114:a0 115:1e 116:6f 117:1a 118:00 119:0a 120: 20 121:20 122:20 123:20 124:20 125:20 126:00 127:8b ************************************************************ MITSUBISHI GS3.chk ************************************************************ Vendor/Product Identification ID Manufacturer Name : PHL ID Product Code : 0005(HEX.) ID Serial Number : 123456(DEC.) Week of Manufacture : 34 Year of Manufacture : 2000 EDID Version, Revision Version : 1 Revision : 2 Basic Display Parameters/Features Video Input Definition : Analog Video Input 0.700V/0.000V (0.70Vpp) without Blank-to-Black Setup Separate Sync Composite Sync without Sync on Green no Serration required Maximum H Image Size : 36 cm Maximum V Image Size : 27 cm Display Transfer Characteristic: 2.67 (gamma) Feature Support (DPMS) : Standby Suspend Active Off Display Type : RGB color display Color Characteristics Red X coordinate : 0.622 Red Y coordinate : 0.339 Green X coordinate : 0.279 Green Y coordinate : 0.6 Blue X coordinate : 0.149 Blue Y coordinate : 0.072 White X coordinate : 0.283 White Y coordinate : 0.297 Established Timings Established Timings I : 720 x 400 @70Hz (VGA,IBM) 640 x 480 @60Hz (VGA,IBM) 640 x 480 @67Hz (Apple,MacII) Established timings II : 800 x 600 @72Hz (VESA) 1024 x 768 @75Hz (VESA) 1280 x 1024 @75Hz (VESA) Manufacturer's timings : Standard Timing Identification #1 Horizontal active pixels : 1920 Aspect Ratio : 4:3 Refresh Rate : 60 Standard Timing Identification #2 Horizontal active pixels : 1792 Aspect Ratio : 4:3 Refresh Rate : 60 Standard Timing Identification #3 Horizontal active pixels : 1600 Aspect Ratio : 4:3 Refresh Rate : 75 Standard Timing Identification #4 Horizontal active pixels : 1280 Aspect Ratio : 5:4 Refresh Rate : 85 720 x 400 @88Hz (XGA2,IBM) 640 x 480 @72Hz (VESA) 640 x 480 @75Hz (VESA) 800 x 600 @60Hz (VESA) 800 x 600 @75Hz (VESA) 832 x 624 @75Hz (Mac II) 1024 x 768 @87Hz ( IBM) 1024 x 768 @60Hz (VESA) 1024 x 768 @70Hz (VESA) 1152 x 870 @75Hz (Mac II) Standard Timing Identification #5 Horizontal active pixels : 1280 Aspect Ratio : 5:4 Refresh Rate : 60 Standard Timing Identification #6 Horizontal active pixels : 1024 Aspect Ratio : 4:3 Refresh Rate : 85 Detailed Timing #1 Pixel Clock (MHz) : 229.5 H Active (pixels) : 1600 H Blanking (pixels) : 560 V Active (lines) : 1200 V Blanking (lines) : 50 H Sync Offset (F Porch) (pixels): 64 H Sync Pulse Width (pixels) : 192 V Sync Offset (F Porch) (lines): 1 V Sync Pulse Width (lines) : 3 H Image Size (mm) : 355 V Image Size (mm) : 265 H Border (pixels) : 0 V Border (lines) : 0 Flags : Non-interlaced Normal Display, No stereo Digital Seperate Sync Positive V Sync Positive H Sync Monitor Descriptor #2 Serial Number : TY 123456 Monitor Descriptor #3 Monitor Name : Philips 109P2 Monitor Descriptor #4 Min. Vt rate Hz : 50 Max. Vt rate Hz : 160 Min. Horiz. rate kHz : 30 Min. Horiz. rate kHz : 111 Max. Supported Pixel : 260 Extension Flag : 0 Check sum : 8B(hex) � Go to cover page Forward Back 9 109P2 GS3 CM25 DDC Instructions Additional information : There are two chips (IC) to store the serial number of monitor as below. DDC IC (with EDID data) OSD IC (EEPROM) To write the serial number of monitor to DDC IC and OSD IC simultaneously. Please follow the indications as below. - Access the factory mode of monitor. - Execute DDCV2A F0.EXE - Follow DDC instructions to write serial number to DDC IC and OSD IC. - Turn off monitor (leave factory mode). - Press OSD button, select MONITOR STATUS, verify the updated serial number of monitor. DDC Instructions Additional information about DDC (Display Data Channel) may be obtained from Video Electronics Standards Association (VESA). Extended Display Identification (EDID) information may be also be obtained from VESA. Pin assignment The 15-pin D-sub connector (male) of the signal cable (3 rows) for DDC feature : Pin No. Assignment Pin No. Assignment 1 Red video input 9 No pin 2 Green video input 10 Logic ground 3 Blue video input 11 Connected to pin 10 4 Connected to pin 10 12 Serial data line (SDA) 5 Ground 13 H.sync/H+V 6 Red video ground 14 V. sync (VCLK for 7 Green video ground DDC) 8 Blue video ground 15 Data clock line(SCL) 5 10 15 1 6 11 This [DDC Module (DDC cable)= 4822 320 12004(=4822 724 27550)] and [DDC V2(DDCV2A .EXE) software(3.5" disk)=3138 106 10065 ] are used for "BU Monitor - Chungli product range" which incorporates a DDC1/DDC2B function that allows bi-directional communication between the monitor and PC system for optimal video configuration. [January 31 2000, Revision 3.3] ,which upgrades the software and service information(4822 727 21027 & 4822 727 21038) , is fully compatible with previous one (DDCV2A F0.EXE). 1. General In case the DDC data memory IC, replaced due to a defect the data contents of this IC have to be re- programmed via a PC. In case of replacement of the video (or deflection) board it is advised to re-soldered DDC IC from the old board onto the new board, in this case the IC dose not need to be re-programmed. 2. DDCV2A.EXE can be used for : EDID Structure Version/Revision Version : 1 Revision : 0 (text file) and Version : 1 Revision : 2 (.hex file) DDC data re-programming (Rear of the monitor) Connection Video cable To video card To printer port (LTP1) To access factory mode: - Turn off monitor (don't turn off PC) - Hold " " and " " simultaneously on the front control panel, then press " ", wait till the OSD menu with characters " factory mode (below OSD menu)" come on the screen of monitor as shown in Fig. 1 . - If OSD menu disappears on the screen of monitor, press " " again (anytime), then the OSD menu comes on the screen again. - using " , " : to select OSD menu. " " : to increase or decrease the setting. - Using " " to confirm the selection. * After alignment of factory mode, turn off monitor (if you do not turn off monitor, the OSD menu is always at the factory mode), then turn on monitor again (at this moment, the OSD menu goes back to user mode). To leave factory mode , Fig 1 00195 109P V3.08 000601 � Go to cover page Forward Back 10 DDC Instructions (Continued) How to write DDC hex files to Monitor Menu Configuration: � � � � � � � � � � Use arrow keys to highlight "Options" under the Setup menu, press "Enter" Tab down to ID Serial Number, use down arrow key to place the asterisk (*) beside "store in DEC with LSB first". Press "control/enter" to save. (Ensure the top asterisk (*) is beside in store in HEX with LSB first.) Use arrow keys to highlight "Load EDID" under the file menu, press "Enter". Use arrow keys to highlight "PHILIPS\", Press "Enter". Use arrow keys to highlight "the model list under subdirect", press "Enter". Use arrow keys to highlight "Write EDID to EEPROM" under the R/W menu, press "Enter". Use arrow keys to highlight "Read from EEPROM" under the R/W menu, press "Enter". Use arrow keys to highlight "Edit EDID Code" under the R/W menu, press "Enter". Verify the ID Serial number on the screen matches the serial number of the unit. Verify EDID Structure Version is "Version :2, Revision :1 Press "ESC" Use arrow keys to highlight "Quit", Press "Enter". File R/W Setup Quit Load EDID Write EDID to EEPROM Options Load txt file (V1.0) Read From EEPROM Barcode format Save EDID Edit EDID Code Save txt File Auto Scan Convert EDID Code Os shell Exit 11 12 109P2 GS3 CM25 DDC Reprogramming Instructions (for PHILIPS models) System Requirements Menu Configuration: General : DDC Module (DDC cable), P/N = 4822 320 12004 An Intel 386 (or above) PC or compatible DOS 6.0 or above DDCV2A.EXE software Connect DDC Cable between PC and Monitor. Turn on Monitor and PC. Access Factory Mode of monitor. Verify Factory Mode by OSD function of monitor. Insert diskette in Drive a: Select Run "DDCV2A F0(Zero).EXE" or Win. (hit the space bar once ) Verify the data and version of DDC application software. It should be : January 31 2000 Revision 3.3 Procedure under DOS Press "Enter" at the introduction screen 00MITS.HEX select for 109P20/00(MITS CRT) File R/W Setup Quit Load EDID Write EDID to EEPROM Options Load txt file (V1.0) Read From EEPROM Barcode format Save EDID Edit EDID Code Save txt File Auto Scan Convert EDID Code Os shell Exit 1.How to change drive How to select .HEX files for different Model numbers Use arrow keys to highlight "Options" under the Setup menu, press "Enter". Press "F2", then press "ESC", fill in "A" or "C". [(If your .HEX files for different Model numbers in drive "A", then fill in "A")., (If your .HEX files for different Model numbers in drive "C", then fill in "C"). Normally, to read DDC data from EEPROM of Monitor is enough.] Press "Enter", then press "ESC" Use arrow keys to highlight "Load EDID" under the File menu, press "Enter" Bring up PHILIPS\ press "Enter" Bring up ..\ 109P2 GSIII select, press "Enter" Bring up ..\ at this highlight area, press "Enter", then go back to last screen � � � � � � � � 2. example: � � Go to cover page Forward Back 11 DDC Instructions (Continued) 109P2 GS3 CM25 How to change the Year, Week & Serial number of Monitor [for PHILIPS(BRANDED) models] �Use arrow keys to highlight "Barcode format", under the Setup menu, press "Enter". � � � � � Bring up : Barcode example : 9925123456 Barcode format : YYWWSSSSSS continued: Barcode example : 9925123456 Barcode format : YYWWSSSSSS ---------------------------------------------------------- Manufacture Year : 1999 Manufacture Week : 25 Serial No. : 123456 Serial No. ASCII : _ TY _ _ 123456 ================================ EDID [16] Week : 19 EDID [17] Year : 09 [Year-1990] EDID [12..15] : 0001e240 EDID [77 -89] : TY data correct ? (Y/N) Y There is a description at the lower of the screen for Barcode format as below. Barcode format : Y,W,S,X,- (year,week,s/no,ignore,fixed) Y stands for "year". W stands for "week". S stands for "s/no (serial number)". X stands for "ignore". Allow user to fill in any 'character' or 'numeric'. - stands for "fixed". User have to fill in Special 'character' or 'numeric' for "AutoScan" if user fill in '-' at "Barcode format :". Use arrow keys to highlight "Auto Scan" under the R/W menu, press "Enter". Bring up: Auto Scan year, week, serial number can be changed. Serial Number Year Code Week Code don't care (If monitor is not at Factory Mode, access Factory Mode at this moment.) Fill in "Barcode data (for instance: 0030123456)" beside AutoScan, press "Enter". After 10 seconds around, bring up: File R/W Setup Quit Write EDID to EEPROM Read From EEPROM Edit EDID Code Auto Scan ---------------------------------------------------------- � Fill in 9925123456, press "Enter" Fill in YYWWSSSSSS, press "Enter" Fill in "Y", don't press "Enter" � � � � � � � � � Press "ESC" "ESC", return to R/W menu. Select "Edit EDID code", press "Enter". Verify "ID Serial No."............. Turn off monitor, then turn on monitor again. Press OSD button, select "MONITOR STATUS", press OSD button again. Verify "SERIALNO". (Leave OSD function). Use arrow keys to highlight "QUIT", press "Enter". * * press "space" TY Factory writing ...100% (58) (f8) (7f) (12). Factory code for each site is as below. Brazil H C (48h,43h) Chungli T Y (54h,59h) Delta G K(47h,4Bh) Juarez Y A(59h,41h) Shenzshen C X(43h,58h) Suzhou BZ (42h,5Ah) Szombathely HD (48h,44h) � Go to cover page Forward Back 12 DDC Instructions (Continued) 109P2 GS3 CM25 How to change the Year, Week & Serial number of Monitor [for PHILIPS(PCEC) models] �Use arrow keys to highlight "Barcode format", under the Setup menu, press "Enter". � � � � � Bring up : Barcode example : 003412345678 Barcode format : YYWWSSSSSSSS continued: Barcode example : 003412345678 Barcode format : YYWWSSSSSSSS ---------------------------------------------------------- Manufacture Year : 1999 Manufacture Week : 34 Serial No. : 12345678 Serial No. ASCII : _ TY _ _ 12345678 ================================ EDID [16] Week : 22 EDID [17] Year : 09 [Year-1990] EDID [12..15] : 00bc614e EDID [77 -89] : TY data correct ? (Y/N) Y There is a description at the lower of the screen for Barcode format as below. Barcode format : Y,W,S,X,- (year,week,s/no,ignore,fixed) Y stands for "year". W stands for "week". S stands for "s/no (serial number)". X stands for "ignore". Allow user to fill in any 'character' or 'numeric'. - stands for "fixed". User have to fill in Special 'character' or 'numeric' for "AutoScan" if user fill in '-' at "Barcode format :". Use arrow keys to highlight "Auto Scan" under the R/W menu, press "Enter". Bring up: Auto Scan year, week, serial number can be changed. Serial Number Year Code Week Code don't care (If monitor is not at Factory Mode, access Factory Mode at this moment.) Fill in "Barcode data (for instance: 003412345678)" beside AutoScan, press "Enter". After 10 seconds around, bring up: File R/W Setup Quit Write EDID to EEPROM Read From EEPROM Edit EDID Code Auto Scan ---------------------------------------------------------- � Fill in 993412345678, press "Enter" Fill in YYWWSSSSSSSS, press "Enter" Fill in "Y", don't press "Enter" � � � � � � � � � Press "ESC" "ESC", return to R/W menu. Select "Edit EDID code", press "Enter". Verify "ID Serial No."............. Turn off monitor, then turn on monitor again. Press OSD button, select "MONITOR STATUS", press OSD button again. Verify "SERIALNO". (Leave OSD function). Use arrow keys to highlight "QUIT", press "Enter". * * press "space" TY Factory writing ...100% (58) (f8) (7f) (12). Factory code for each site is as below. Brazil H C (48h,43h) Chungli T Y (54h,59h) Delta G K(47h,4Bh) Juarez Y A(59h,41h) Shenzshen C X(43h,58h) Suzhou BZ (42h,5Ah) Szombathely HD (48h,44h) � Go to cover page Forward Back 13 109P2 GS3 CM25 Electrical Adjustments 31.469 KHz/70.087 Hz, 640 X 350 31.469 KHz/59.941 Hz, 640 X 480 31.468 KHz/70.084 Hz, 720 X 400 37.5 KHz/75 Hz, 640 X 480 37.861 KHz/72.810 Hz, 640 X 480 37.861 KHz/85.081 Hz, 640 X 350 37.879 KHz/60.317 Hz, 800 X 600 37.927 KHz/85.039 Hz, 720 X 400 43.269 KHz/85.008 Hz, 640 X 480 46.875 KHz/75.000 Hz, 800 X 600 48.077 KHz/72.188 Hz, 800 X 600 48.363 KHz/60.004Hz, 1024X 768 49.722 KHz/74.546Hz, 832 X 624 50.628 KHz/100.10 Hz, 640 X 480 53.674 KHz/85.061 Hz, 800 X 600 56.476 KHz/70.069 Hz,1024X 768 60.000 KHz/60.000 Hz,1280 X 960 60.023KHz/75.029Hz, 1024 X 768 63.923 KHz/100.00 Hz, 800 X 600 63.981KHz/60.020Hz, 1280 X 1024 67.500 KHz/75.00Hz, 1152 X 864 68.677KHz/84.997Hz, 1024 X 768 68.681KHz/74.979Hz, 1152 X 870 71.809KHz/76.15 Hz, 1152 X 900 75.000KHz/60.000 Hz, 1600 X 1200 79.976KHz/75.024 Hz, 1280 X 1024 81.250 KHz/65.000 Hz, 1600 X 1200 83.640 KHz/59.999 Hz, 1792 X 1344 85.938 KHz/85.002 Hz, 1280 X 960 86.333 KHz/59.995 Hz, 1856X 1392 87.500 KHz/70.000 Hz, 1600 X 1200 90.000 KHz/60.000 Hz, 1920 X 1440 91.146 KHz/85.024 Hz, 1280 X 1024 93.750 KHz/75.000Hz, 1600 X 1200 106.250KHz/85.00 Hz, 1600 X 1200 106.270KHz/74.997Hz, 1792 X 1344 0. General 1. B+ supply voltage (3157) 210Vdc 2. High-voltage EHT (3698) When carry-out the electrical settings in many cases a video signal must be applied to the monitor. A computer with : - ATI GPT-1600 (4822 397 10065), Mach 64 (up to 107kHz) are used as the video signal source. The signal patterns are selected from the "service test software" package, see user guide 4822 727 21046 (GPT-1600). The measurements for AC waveform and DC figure is based on 640 x 480 31.5 kHz/60 Hz resolution mode with test pattern "gray scale". Power input: 110V AC - Apply a video signal in the 1024 x 768 with 68.7 kHz/85Hz mode. - Select the "cross-hatch" pattern. - Set the brightness control and the contrast control to the minimum position. - Pre-set trimming potentiometer 3157(B+) and 3698(EHT) in mid-position. - Set Vg2 (screen) to fully Counter-clockwise (zero beamcurrent). - Connect a dc voltmeter between the joint of capacitor 2131 and ground (common ground). - Set the B+ trimming potentiometer 3157 so that the reading on the dc voltmeter is 210 V +/- 0.5 Vdc. - Apply a video signal in the 1024 x 768 with 68.7 kHz/85Hz mode. - Select the "cross-hatch" pattern. - Set the brightness control and the contrast control to the minimum position. - Turn off the power. 0.1 This monitor has 35 factory-preset modes as below . 0.2 With normal VGA card: If not using the ATI card during repair or alignment, The service engineer also can use this service test software adapting with normal standard VGA adaptor and using standard VGA mode 640 x 480, 31.5 kHz/60 Hz (only) as signal source. 0.3 AC/DC Measurement: 00195 109P V3.08 000601 - Connect a "high-voltage voltmeter" between the high- voltage connection of the picture tube and earth. - Turn on the power. - Set the EHT trimming potentiometer 3698 so that the "high- voltage voltmeter" reads 25.0 kV +/- 0.2 kV . - Turn off the power. - Remove the "high-voltage voltmeter" from the picture tube. - Turn on the power again. 4.5 Adjust function controls " " to center position except for contrast control which should be set to MAX. - Turn off monitor (don't turn off PC) - Press " " and " " simultaneously on the front control panel, then press " ",wait till the OSD menu with characters " factory mode (below OSD menu)" come on the screen of monitor. - If OSD menu disappears on the screen of monitor, press " " again (anytime), then the OSD menu comes on the screen again. - using " " : to select OSD menu. : to increase or decrease the setting. - Using " " to confirm the selection. 5. To access factory mode: 3. Monitor the following auxiliary voltages. 4. General conditions for alignment SOURCE ACROSS C2362 + 8.0V +/- 0.5VDC. SOURCE ACROSS C2143 + 5.0V +/- 0.5VDC. SOURCE ACROSS C2362 +12.0V+/- 0.5VDC. SOURCE ACROSS C2134 +15.0V +/- 1.0VDC. SOURCE ACROSS C2137 - 15.5V +/- 1.0VDC. SOURCE ACROSS D6148"+" 6.3 V+/- 0.5VDC. SOURCE ACROSS C2131 + 210.0V +/-1.5VDC. SOURCE ACROSS C2133 + 82.7 V +/-2.0VDC. 4.1 During all alignments, supply a distortion free AC mains voltage to set via an isolating transformer with low internal impedance. 4.2 Align in pre-warmed condition, at least 30 minutes warm- up with nominal picture brightness. 4.3 Purity, geometry and subsequent alignments should be carried out in magnetic cage with correct magnetic field. Northern hemisphere : H=0, V=430+/-50 mG, Z=0 Southern hemisphere : H=0, V=-520+/-50 mG, Z=0 Equatorial Support : H=0, V=0 mG, Z=0 4.4 All voltages are to be measured or applied with respect to ground. Note: Do not use heatsink as ground. � Go to cover page Forward Back 14 109P2 GS3 CM25 Electrical Adjustments (Continued) 6 To leave factory mode * After alignment of factory mode, turn off monitor (if you do not turn off monitor, the OSD menu is always at the factory mode), then turn on monitor again (at this moment, the OSD menu goes back to user mode). TIMER Set OSD display time. 5500 K R cutoff = 30%, R gain = 70% (I C) G cutoff = 30%, G gain = 70% (I C) B cutoff = 30%, B gain = 70% (I C) 2 2 2 2 2 2 2 2 2 � 7. Alignment of Vg2 cut-off point, white tracking (OSD control) Equipment : 1. Video Test Generator-801GC (Quantum Data) 2. Color-analyzer (Minolta CA-100) VG2 [(screen), at the bottom of the L.O.T.]. * Apply a video signal in the 1024 x 768 with 68.7 kHz/85 Hz mode, select the "full white pattern" (sizes 355 x 265 mm). * Use color-analyzer (Minolta CA-100) to adjust cutoff and white uniformity. OSD R/G/B cut-off and R/G/B gain can be accessed, with initial data: 9300 K R cutoff = 30%, R gain = 70% (I C) G cutoff = 30%, G gain = 70% (I C) B cutoff = 30%, B gain = 70% (I C) 6500 K R cutoff = 30%, R gain = 70% (I C) G cutoff = 30%, G gain = 70% (I C) B cutoff = 30%, B gain = 70% (I C) Brightness = 50%, Sub-Contrast = 90%, ABL = 50% (I C) Step 1: To select the character "FACTORY MODE" as shown in Fig. 2.1, press " " to access the OSD menu for R/G/B gain & cutoff as shown in Fig. 2.2. Step 2: Press " " for function selection as shown in Fig 2.3. Step 3: Use " " to increase or decrease the value as shown in Fig. 2.3. � � 2 Fig.2.1 00195 109P V3.08 000601 . RIGHT, 7.1 Connect the video input, set brightness control at 50% and contrast at minimum position (OSD), Vg2 at Minimum (counter clockwise, and ABL (OSD) at 50% position. Slowly increase Vg2 voltage until light output is at 0.1 Ft-L +/- 0.01Ft-L (Y=0.1 Ft-L, on the screen of CA-100). 7.2 (The screen of monitor is dark now) : Press " " to show the OSD menu as shown in Fig. 2.1. : Select the character "FACTORY MODE" to access the R/G/B adjustment as shown in Fig. 2.2 and Fig. 2.3. : Adjust the cutoff of R/G/B to get 9300K (x=0.283 +/- 0.015, y=0.297 +/- 0.015), and brightness output at 0.07 +/- 0.01 Ft-L (Y=0.07Ft-L). 7.3 : Press " " to set contrast at maximum (100%). : Adjust gain of R/G/B to get 9300K (x=0.283 +/- 0.015, y=0.297 +/-0.015, don't care about the Y value) 7.4 Apply a small white square 10 x 10 cm pattern, brightness set to center (50%), and contrast at maximum (100%), adjust Sub-contrast control (OSD) to reach 32 +/- 2 Ft-L. 7.5 Apply full white pattern at 9300K, adjust ABL (OSD) to reach 32+/- 2 Ft-L (contrast at maximum 100%, brightness at center 50%). BIAS R G B : R(red) G(green) B(blue) cutoff GAIN R G B : R(red) G(green) B(blue) gain V FOCUS : Vertical Focus H FOCUS : Horizontal Focus VLIN BAL : Vertical Linearity Balance USER : Horizontal size range RASTER H: Horizontal raster Shift RASTER V: Vertical raster Shift HLIN : Horizontal Linearity V LIN : Vertical Linearity SUB : Zoom Control range SUB : Sub Contrast V OFFSET : Vertical offset V GAIN : Vertical Gain ABL : Auto Beam Limit T CORNER: Corner Correction of TOP B CORNER: Corner Correction of BOTTOM CONVERGENCE(V H R):CONVERGENCE Correction of Vertical , Horizontal,Corner (RESERVED). NS IMPURITY(BR TR BL TL):NS IMPURITY Correction of BOTTOM TOP BOTTOM LEFT, TOP LEFT. RIGHT, After pressing " " ,then Press " " Fig. 2.2 Fig. 2.3 107 � Go to cover page Forward Back 15 109P2 GS3 CM25 Electrical Adjustments (Continued) 7.6 : Select the 6500K colour temperature as shown in Fig. 2.2. : Adjust the R/G/B cutoff and R/G/B gain as shown in procedure 7.2~7.3 to get R/G/B cutoff x= 0.313 +/- 0.015 y= 0.329 +/- 0.015 R/G/B gain x= 0.313 +/- 0.015 y= 0.329 +/- 0.015 Y= 28 +/- 2 Ft-L(Adjust Sub-contrast control (OSD)) 7.7 : Select the 5500K colour temperature as shown in Fig. 2.2. : Adjust the R/G/B cutoff and R/G/B gain as shown in procedure 7.2~7.3 to get R/G/B cutoff x= 0.332 +/- 0.015 y= 0.347 +/- 0.015 R/G/B gain x= 0.332 +/- 0.015 y= 0.347 +/- 0.015 Y= 25 +/- 2 Ft-L(Adjust Sub-contrast control (OSD)) - Apply a video signal with cross-hatch pattern. - Apply a video signal in the 1024 x 768 with 68.7 kHz/85 Hz mode. - Set brightness and contrast controls to their center positions (OSD control). 8. Picture geometry setting (factory pre-set modes) 8.1 Horizontal geometry (OSD control) - Adjust the H-width to 355 mm - Adjust the H-phase to center position. 8.2 Vertical geometry (OSD control) - Adjust vertical size to 265 mm - Adjust V-phase to center position. 8.3 Trapezoid distortion (OSD control) - Adjust the trapezoid to get optimal vertical lines. 8.4 Pincushion (OSD control) - Adjust the pincushion to get optimal vertical line. 8.5 Parallelogram (OSD control) - Adjust parallelogram so that vertical lines are vertical or symmetrically about the center vertical axis. 8.6 Unbalance-pin (OSD control) - Adjust the unbalance-pin so that that vertical border lines are aligned symmetrically. 8.7 Rotation (OSD control) - Adjust picture so that vertical tilt is less than +/- 0.5mm. 8.8 Top/Bottom corner(control) - Adjust the top/bottom corner control to get optimum corner geometry. 8.9 Store the preset results by selecting the "exit" (OSD control). 8.10 Repeat the procedure 8.1 to 8.9 until all the preset timings have been adjusted completely 9. Focus adjustment 10. Loading DDC code : Apply a video signal in the 1024 x 768 with 68.7 kHz/85 Hz mode : Select " @ " pattern. : Set the brightness at center (50%) and the contrast to 22 FL. : Adjust focus potentiometers (top of L.O.T.) Focus 1 for horizontal focus and Focus 2 for vertical focus so that the picture at 2/3 of the diagonal lines (from center to four corners) of the displayed screen is as sharp as possible. The DDC HEX data should be written into the DDC IC by EEPROM writer or equivalent method. a: Service DDC Kit DDC Module (DDC cable), Part number = 4822 320 12004 DDCV2A.EXE software (3.5" disk), Part number = 3138 106 10065 b: Please refer to Service information 4822 727 21027(4822 727 21038) for using the Service DDC Kit. � Go to cover page Forward Back 16 109P2 GS3 CM25 1. Purity adjustment 2. Static convergence - Make sure the monitor is not exposed to any external magnetic field. - Produce a full red pattern on the screen, adjust the purity magnet rings on the PCM assy (on CRT) to obtain a complete field of the color red. This is done by moving the two tabs (2-pole) in such a manner that they advance in an opposite direction but at the same time to obtain the same angle between the two tabs, which should be approximately 180 degree. - Check by full green pattern and full blue pattern again to observe their respective color purity. Introduction Slight deviation in the static convergence can be corrected by using two permanent pairs of magnets which are fitted around the neck of the CRT. These are the 4-pole magnet and the 6-pole magnet. The 4-pole magnet move the outermost electron beams (R and B) parallel in the opposite direction from the other. The 6-pole magnet moves the outermost electron beam (R, B and G) parallel in the opposite direction from the other. The magnetic field of the above magnets do not affect the center of the CRT neck. Setting - Before the static convergence setting can be made, the monitor must be switched on for 30 minutes. - The focus setting must be made correctly. - Signal: 640 * 480, 31.5 kHz/60 Hz mode. - Set the tabs of the 4-pole magnet in the neutral position. This is when the tabs are opposite one another. In this position the magnets do not affect the deflection of the R and B electron beams. - Set the tabs of the 6-pole magnet in the neutral position. This is when the tabs are opposite one another. In this position the magnets do not affect the deflection of the R, B, and G electron beams. - First set the 4-pole magnet optimally. - Then set the 6-pole magnet optimally. - If the convergence is not now optimal, then adjust to the optimal setting with the 4-pole magnet and then with the 6- Pole magnet again. - Set the tabs of the 6-pole magnet in the neutral position. This is when the tabs are opposite one another. In this position the magnets do not affect the deflection of the R, B, and G electron beams. - First set the 4-pole magnet optimally. - Then set the 6-pole magnet optimally. - If the convergence is not now optimal, then adjust to the optimal setting with the 4-pole magnet and then with the 6- pole magnet again. 2-pole purity magnet 6-pole convergence magnet 4-pole convergence magnet Deflection Yoke 4-pole Beam motion producced by the 4-pole convergence magnet S S N N B G R S S N N B G R Beam displacement direction Magnetic flux lines 6-pole Beam motion producced by the 6- pole convergence magnet S S S N N N R B G S S S N N N R B G Purity and Convergence Adjustments � Go to cover page Forward Back 17 109P2 GS3 CM25 Mechnical Instructions Fig. 5 Fig. 4 Fig. 3 Fig. 6 Fig. 8 Fig. 2 Fig. 7 screw 0. Location of the panel 1. General Chassis : Video panel : Main panel : Service position : 2. Repair instructions 0.1 Main panel (1160) 0.2 Video panel (1162) To be able to perform measurements and repairs on the "circuit boards", the monitor should be placed in Service Position (fig. 1) first: There are 2 screws in the lid [1 screw are at the right side of the monitor, The other 1 screw are at the left side of the monitor],to fix the front cabinet and back cover of the monitor. Step 1: To open the lid at the right-upper side and 1 right- downer side of the monitor.(FIG.3) Step 2: To open the lid at the left-upper side and left- downer side of the monitor.(FIG.4) Step 3: To remove the back cover, you can see FIG.5 Step 4: To remove the16 screws on the metal shield, and remove the metal shield, you can see FIG.6. - After remove the back cover & metal shield, you can see the inside of the monitor as Fig. 6. - To remove 16 screws for service position as Fig. 5 to Fig. 8. - Include remove bottom plate screw, then slide out chassis board and disconnect metal shield. - After remove the metal frame (Fig. 5), to remove the metal shield on rear side of Video panel for measurement. After remove the metal frame. - To cut out cable tie and disconnect "video panel" - To disconnect EHT cable - To disconnect ground wire(1703) of video board. - To disconnect M1311(4pin) to control panel. - To disconnect M1501(4pin) yoke connector. - To disconnect M1131(2pin) degaussing coil - To slide out Main panel as Fig. 1. To get service position as Fig. 1 through Fig. 2 to Fig. 8. After the service position was obtained, all the panel's copper track side could be accessed. How to remove the back cover of monitor : screw in 1screw in Fig. 1 Service Position 1162 lids screws screws 1160 � Go to cover page Forward Back Safety test requirements 18 109P2 GS3 CM25 2.2.1 The test with AC voltage is only for production purpose, Service center shall use DC voltage. 2.2.2 2.2.3 2.2.4 The grounding blade or pin of mains plug must be conducted with accessible metal parts. The minimum test duration for Quality Control Inspector must be 1 minute.No breakdown during the test. The test voltage must be maintained within the specified voltage + 5%. All units that are returned for service or repair must pass the original manufactures safety tests. Safety testing requires both and testing. Hipot Ground Continuity HI-POT TEST INSTRUCTION 1. Application requirements 2. Test method 1.1 All mains operated products must pass the Hi-Pot test as described in this instruction. 1.2 This test must be performed again after the covers have been refitted following the repair, inspection or modification of the product. 2.1 Connecting conditions 2.1.1 The test specified must be applied between the parallel- blade plug of the mainscord and all accessible metal parts of the product. 2.1.2 Before carrying out the test, reliable conductive connections must be ensured and thereafter be maintained throughout the test period. 2.1.3 The mains switch(es) must be in the "ON" position. 2.2 Test Requirements All products should be HiPot and Ground Continuity tested as follows: Test 2820VDC 1700VDC Test current: voltage (2000VAC) (1200VAC) 25A,AC Test time: Test time 3 seconds 1 second 3 seconds(min.) (min.) Resistance required: Trip set at 100 uA 5 mA <=0.09+R ohm, current for Max. R is the (Tester) limitation; set resistance of at 0.1 uA for the mains cord. Min. limitation Ramp set at 2 time seconds Condition HiPot Test for HiPot Test for Ground Continuity products where products where Test requirement the mains input the mains input is range is Full 110V AC(USA range(or 220V type) AC) 3. Equipments and Connection 4. Recording 3.1. Equipments For example : - ChenHwa 9032 PROGRAMMABLE AUTO SAFETY TESTER - ChenHwa 510B Digital Grounding Continuity Tester - ChenHwa 901 (AC Hi-pot test), 902 (AC, DC Hi-pot test) Withstanding Tester 3.2. Connection Hipot and Ground Continuity testing records have to be kept for a period of 10 years. * Turn on the power switch of monitor before Hipot and Ground Continuity testing. Connect the "video cable" or "grounding screw" to the CLIP on your tester. Video cable (Rear view of monitor) Connect the power cord to the monitor. Grounding screw Power outlet (ChenHwa 9032 tester) Clip Clip � Go to cover page Forward Back 19 109P2 GS3 CM25 Wiring Diagram 1502 1703 1311 1501 8002 8001 1006 1003 1705 1712 8701 TO VIDEO 1703 GRAY WHITE TO HVG RED TO DRVIER PCD 1206 TO MAIN PCB 1502 8004 INSERT CRT NECK SCREW(DOWN) EARTH WIRE 1706 INSERT CRT NECK SCREW (UP) GRAY WAFER A 3138 103 5335 PIN B, C METAL SHIELD-FRONT (SIDE VIEW ) INSERT BOTTOM PLATE PIN E INSERT METAL SHIELD-FRONT PIN B PIN F INSERT BOTTOM PLATE PIN F INSERT METAL SHIELD-FRONT PIN C OPTIONAL ITEM MHR PCB ASSY TO 1192 (MHR PCB OPTION) PIN E (WITHOUT MHR PCB) 8003 MAIN PCB TO WAFER A 1131 8106 TO 1193 (MHR PCB OPTION) BNC ASSY TO MAIN BOARD 1131 DEGAUSS COIL 1206 1204 1203 1201 DRIVER PCB PIN E 3138 103 5352 1192 1193 � Go to cover page Forward Back Block Diagram 20 109P2 GS3 CM25 Pre-Amp TDA4886A Post-Amp LM2402 OSD MC141545 Sync Processor TDA4856 Power Supply Degaussing Rotation EHT X-RAY Linearity Control DAF Cs SW Horizontal Deflection Vertical STV9379 Muting & G1 Spot Killer CRT Sync Switch DDC 1/2B BNC D-SUB V’ H” H V HUNLOCK MUTE B+ HDRV G1 +210 +81 +15 -15 +6.3 SDA SCL Horizontal Frequency : 30~111kHz Vertical Frequency : 50~160 Hz CM25+ 109P 19” MONITOR SDA/SCL (DDC) . . . H’ Auto Calibrate USB device D11 CPU P83C380 . . V V ” . Signal Selector DC Restore (discrete) R G B . Purity & convergence correction � Go to cover page Forward Back Terminal Schematic Diagram PCB (A1) 21 A1 A16 A16 A16 A20 A20 A20 A19 A18 A17 4V3 4V5 6V1 6V2 6V2 2V8 2V8 2V8 2V8 2V8 2V8 4V 109P2 GS3 CM25 2 � Go to cover page Forward Back Video Schematic Diagram A2 109P2 GS3 CM25 32 22 PCB(A2) A4 A15 A14 A14 A14 A13 A13 A13 A12 A12 A12 A11 A10 A9 A8 A7 A6 A6 A6 A5 A5 A5 A4 A4 A3 A3 A3 A2 A2 A2 A1 A1 A1 2701 A3 3768 C3 1703 B3 2702 A3 3769 C3 1705 C2 2707 A3 3781 B3 1706 C1 2708 A3 3782 A3 1710 B2 2709 A3 3783 B3 1711 B2 2710 A2 3784 B3 1712 C1 2720 A2 3785 A3 2704 A2 2721 A3 3786 A3 2705 A3 2722 A3 3787 A3 2706 B1 2727 A3 3788 A3 2724 A3 2732 A3 3789 A3 2725 A3 2736 A3 3790 A3 2726 B2 2740 A3 3791 A3 2744 A2 2741 A3 3792 A3 2745 B3 2742 A3 3801 C3 2746 B1 2747 A3 3802 C3 2748 A1 2749 A2 3803 C3 2752 A3 2750 A2 3804 C3 2753 A2 2751 A2 3805 B3 2761 B1 2760 B2 3806 C3 2762 B1 2771 C2 3807 C3 2763 C2 2773 C2 3808 C3 2764 B1 2774 C2 3809 C3 2765 B1 2776 C1 3811 A2 2770 C2 2778 C1 3812 A2 2772 C2 2783 C3 3813 A2 2775 C2 2784 C3 3814 A2 2777 C2 2785 C3 3815 A2 2779 C3 2786 C3 3816 B3 2780 C3 2787 C3 3821 A3 2781 C3 2788 C3 3822 A3 2782 C2 2789 C3 3823 A3 2791 A1 2790 C2 3824 A2 2798 B1 2792 A3 3825 A3 2811 A3 2793 A3 3831 A1 3706 A3 2794 B3 3832 B1 3707 A3 2795 B3 3833 B1 3709 A2 2796 A3 3834 B1 3726 B3 2799 B3 3835 B1 3727 B3 2801 C3 3836 C3 3729 B2 2802 C3 3841 B3 3746 B3 2803 C3 3842 C3 3747 C3 2804 C3 3843 B3 3749 B1 2805 C3 3844 B3 3752 A2 2806 C3 3845 B3 3753 A3 2807 B3 3846 B3 3754 A1 2812 A2 5703 A1 3760 B1 2813 A2 5722 B1 3761 B1 2814 B3 5732 B1 3763 C1 2815 C3 5733 C2 3765 C3 2821 A3 5735 A2 3847 A1 2822 A2 5736 A2 3848 B1 2831 A1 5737 A2 5701 A1 2832 B1 5761 C2 5702 A2 3701 A3 5762 C2 5721 A3 3702 A3 5763 C1 5731 A1 3703 A3 5764 C1 5734 A1 3704 A2 5765 C1 5760 B3 3705 A2 5801 A2 5766 C3 3708 A1 6701 A2 5767 B1 3710 A1 6702 A2 5768 C1 3711 A1 6703 A1 5781 B1 3712 A3 6704 A1 5782 A1 3713 A3 6705 A1 5783 B1 3714 A3 6721 A1 5791 B1 3715 A3 6722 A1 6761 C2 3716 A3 6723 A1 6762 C3 3717 A3 6724 B1 7701 A1 3718 A3 6725 B1 7705 A2 3719 A1 6731 A3 7706 A3 3720 A1 6732 A3 7707 A3 3721 A3 6741 A3 7726 B3 3722 A3 6742 A3 7727 B3 3723 A3 6743 B1 7746 C3 3724 A2 6744 B1 7747 C3 3725 A2 6745 C1 7781 A1 3728 B1 6763 C3 7801 C1 3730 B1 6764 C3 7802 B1 3731 B1 6801 C3 7803 A2 3732 A3 6802 C3 7804 A1 3733 A3 6803 B3 7805 B3 3734 A3 6811 A2 7806 B1 3735 A3 6812 A2 7808 A2 3736 A3 6813 B3 7809 A2 3737 A2 6821 A3 7810 A1 3738 A2 6822 A2 8701 A1 3739 B1 6823 B3 3740 B1 6831 A1 3741 A3 6832 B1 3742 A3 6833 B3 3743 A3 7782 A3 3744 A3 7783 A3 3745 A2 7807 C3 3748 B1 3750 C1 3751 C1 3758 C1 3759 C1 3766 C3 3767 C3 � Go to cover page Forward Back 23 109P2 GS3 CM25 Deflection Schematic Diagram B3 B1 B36 B37 B38 B39 B40 B41 B43 B47 B49 B50 B51 B44 B45 B46 B48 B42 B33 B35 B34 B28 B29 B30 B31 B32 B27 B26 B25 B20 B21 B22 B23 B14 B15 B13 B10 B11 B17 B18 B16 B19 B24 B12 B9 B8 B7 B6 B5 B4 B2 B1 B � Go to cover page Forward Back 24 109P2 GS3 CM25 A16 7001-3 A20 7001-27 A16 7001-7 A20 7001-29 A16 7001-11 A20 7001-23 A19 7001-19 A17 7001-16 0.5 V/div AC 5 mS/div 1 V/div AC 5 mS/div 0.5 V/div AC 5 mS/div 1 V/div AC 5 mS/div 0.5V/div AC 5 mS/div 0.5V/div AC 5 mS/div 1V/div AC 5 mS/div 1V/div AC 10 uS/div 0.5 V/div AC 5 mS/div A18 7001-18 C1 5130-1 C8 5130-12 C2 5130-3 C9 7111-B C3 5130-5 C10 7163-B C12 7130-3 C7 5130-18 C6 5130-18 C4 5130-5 C11 7130-4 10 V/div AC 2 uS/div 10 V/div AC 5 mS/div 5 V/div AC 2 uS/div 5 V/div AC 5 mS/div 0.5 V/div AC 2 uS/div 5 V/div AC 5 mS/div 0.2 V/div AC 2 uS/div 10 V/div AC 5 mS/div 5 V/div AC 5 mS/div 5 V/div AC 5 mS/div 0.5 V/div AC 2 uS/div 5 V/div AC 5 mS/div C5 5130-9 Waveform (A) Waveform (B) Waveform (C) S A1 8701-6 A1 8701-4 A1 8701-2 A2 7701-8 A2 7701-10 A3 7701-22 A2 7701-6 50 mV/div AC 5 mS/div 50 mV/div AC 5 mS/div 50 mV/div AC 5 mS/div 1 V/div AC 5 mS/div 0.5 V/div AC 5 mS/div 0.5 V/div AC 5 mS/div 0.5 V/div AC 5 mS/div A13 7805-B A10 7802-8 A14 7803-C A11 7801-5 A14 7804-C A12 7809-C A15 7802-2 A12 7808-C A13 7804-B A13 7803-B A14 7805-C A12 7810-C 10 V/div AC 5 mS/div 1 V/div AC 5 mS/div 1 V/div AC 5 mS/div 1 V/div AC 5 mS/div 1 V/div AC 5 mS/div 10 V/div AC 5 mS/div 0.5 V/div AC 5 mS/div 10 V/div AC 5 mS/div 10 V/div AC 5 mS/div 10 V/div AC 5 mS/div 1 V/div AC 5 mS/div 10 V/div AC 5 mS/div A5 7705-5 A3 7701-19 A6 1710-11 A3 7701-16 A6 1710-8 A4 7705-9 A7 7781-5 A4 7705-8 A5 7705-1 A8 7781-10 A9 7782-B A5 7705-3 A6 1710-6 A4 7705-11 5 V/div AC 5 mS/div 1 V/div AC 5 mS/div 10 V/div AC 5 mS/div 1 V/div AC 5 mS/div 10 V/div AC 5 mS/div 0.5 V/div AC 5 mS/div 1 V/div AC 5 uS/div 1 V/div AC 5 mS/div 0.5 V/div AC 5 mS/div 0.5 V/div AC 5 mS/div 5 V/div AC 5 mS/div 5 V/div AC 5 mS/div 10 V/div AC 5 mS/div 0.5 V/div AC 5 mS/div B22 7502-B B29 7543-C B36 7301-13 B1 7404-14 B43 7651-1 B8 7421-17 B50 5671-1 B15 7422-E B23 7502-C B30 7543-B B37 7301-14 B2 7404-13 B44 7651-10 B9 7421-24 B51 5671-12 B16 7566-B B24 5503-5 B31 5601-4 B38 7301-16 B3 7404-12 B45 7671-G B10 7421-11 B17 7567-6 B25 7461-C B26 7491-7 B33 7301-4 B40 7301-42 B47 7672-D B27 7425-E B28 7541-D B35 7301-10 B42 7651-2 B7 7421-16 B49 567-3 B14 7422-B B34 7301-9 B41 7351-3 B6 7404-2 B48 5671-9 B13 7421-29 B20 7567-4 B32 7622-11 B39 7301-18 B4 7404-15 B46 7671-D B11 7421-12 B18 7567-3 5 V/div AC 5 uS/div 100 V/div AC 5 uS/div 2 V/div AC 10 uS/div 2 V/div AC 5 mS/div 2 V/div AC 5 uS/div 0.5 V/div AC 5 mS/div 100 V/div AC 5 uS/div 5 V/div AC 5 uS/div 100 V/div AC 5 uS/div 100 V/div AC 5 uS/div 2 V/div AC 5 uS/div 2 V/div AC 5 mS/div 5 V/div AC 5 uS/div 2 V/div AC 5 mS/div 100 V/div AC 5 uS/div 10 V/div AC 5 mS/div 50 V/div AC 5 uS/div 100 V/div AC 5 mS/div 2 V/div AC 5 mS/div 2 V/div AC 5 mS/div 5 V/div AC 5 uS/div 1 V/div AC 5 mS/div 10 V/div AC 5 mS/div 5 V/div AC 5 mS/div 2 V/div AC 5 mS/div 100 V/div AC 5 uS/div 5 V/div AC 5 uS/div 2 V/div AC 20 uS/div 2 V/div AC 50 uS/div 2 V/div AC 50 uS/div 2 V/div AC 20 uS/div 0.5 V/div AC 5 uS/div 1 V/div AC 50 uS/div 0.2 V/div AC 10 uS/div 100 V/div AC 5 uS/div 2 V/div AC 5 uS/div 100 V/div AC 5 uS/div 0.2 V/div AC 10 uS/div 100 V/div AC 5 uS/div 5 V/div AC 5 mS/div 5 V/div AC 5 US/div 2 V/div AC 5 uS/div 20 V/div AC 5 mS/div 5 V/div AC 5 mS/div 20 V/div AC 5 uS/div 0.1 V/div AC 5 mS/div 0.2 V/div AC 10 uS/div 5 V/div AC 5 uS/div 0.5 V/div AC 2 mS/div 10 V/div AC 5 mS/div B5 7404-1 B12 7421-32 B19 7567-5 B21 5501-5 50 V/div AC 5 uS/div 5 � Go to cover page Forward Back 25 109P2 GS3 CM25 PCB (B, C) 1101 F1 2579 E7 3421 E8 3633 C5 6540 D3 9143 E5 9535 A7 2123 G4 3624 D6 1102 G2 2586 G8 3422 E8 3634 C5 6541 D5 9144 F5 9541 E7 2125 G5 3626 D6 1103 G1 2587 G7 3424 E8 3653 C1 6542 D3 9148 F6 9542 E6 2154 F5 3628 D6 1130 E2 2588 G7 3426 D8 3658 B1 6543 D4 9311 B8 9543 G7 2155 F6 3630 D6 1131 E1 2589 G7 3427 D8 3659 B1 6544 B3 9312 A8 9544 E6 2161 E1 3632 D6 1134 E1 2601 D3 3428 F9 3671 B2 6545 A3 9314 A8 9546 D2 2162 G5 3652 B1 1301 B9 2602 C4 3432 E9 3672 C3 6566 F8 9315 A8 9547 B1 2302 B9 3654 B1 1302 D1 2603 D3 3433 E9 3674 C1 6567 F7 9335 B8 9548 E2 2309 B9 3655 B1 1303 D1 2604 C3 3441 F8 3675 C1 6573 F6 9336 B8 9549 E6 2310 B8 3656 B1 1306 G9 2605 C3 3442 F9 3676 D1 6601 C3 9337 B8 9601 C3 2313 B9 3657 B1 1311 A9 2608 C3 3443 E9 3677 C1 6602 D2 9341 B7 9901 D6 2314 B9 3660 C1 1501 B5 2611 D2 3450 F9 3678 C1 6603 C3 9342 B7 9902 E8 2315 B8 3661 C1 1502 G7 2613 D2 3456 F8 3679 C1 6621 D5 9343 B7 9903 E8 2337 A9 3662 C1 2102 F2 2620 B6 3458 A3 3680 C1 6622 D5 9344 B7 9904 G8 2338 A9 3663 B1 2103 F3 2621 C6 3462 E7 3681 C1 6651 C1 9345 B7 9905 G6 2345 D1 3664 D1 2104 G3 2622 C6 3465 D9 3682 A1 6652 B1 9346 B7 9906 D8 2351 D1 3665 D1 2111 G5 2623 C6 3466 D9 3683 B1 6655 D1 9347 B7 9908 B8 2352 D1 3666 D1 2112 G5 2624 C6 3468 F9 3684 A1 6671 C2 9401 E6 9909 A8 2353 D1 3667 D1 2115 G6 2625 C5 3469 F9 3685 A1 6672 C1 9403 C1 9911 D7 2391 C7 3668 C1 2116 F5 2626 C5 3470 F8 3689 A7 6673 C1 9404 C1 9912 D7 2392 D8 3673 A1 2121 G4 2627 C5 3471 F9 3690 A8 6674 C2 9405 C1 9913 D7 2424 E7 3686 A1 2122 G4 2632 C6 3472 F8 3691 A1 6691 A1 9406 F9 9914 D7 2442 E9 3687 A1 2124 G3 2635 C5 3473 F7 3692 A1 7111 G6 9407 B1 9915 D7 2443 E9 3688 A1 2127 E1 2636 C5 3474 F8 3693 A1 7121 G4 9408 A1 9916 D7 2444 E9 3700 C1 2128 F2 2651 B1 3475 F7 3694 A1 7130 F5 9411 A7 9917 D6 2462 E7 5354 D1 2129 F2 2655 B1 3476 F8 3695 A1 7140 E5 9412 D1 9918 D6 2464 E7 5355 E1 2130 F3 2656 C1 3493 B8 3696 A2 7143 F6 9413 C4 9919 C7 2492 B8 6114 G4 2131 E2 2659 D1 3495 B8 3697 A1 7144 F5 9414 A4 9920 C7 2493 B8 6160 E2 2133 E3 2671 C3 3501 B7 3698 A1 7146 E5 9416 D5 9921 A5 2545 E7 6162 E5 2134 E4 2673 C1 3502 B6 4120 G3 7151 F6 9417 D2 9922 D7 2546 E7 6301 B8 2135 E3 2682 D2 3503 A7 4121 G4 7155 F6 9420 D2 9923 E3 2612 D2 6391 C8 2137 E4 2683 C2 3504 A7 4301 E7 7161 E1 9421 D2 9924 D6 2652 B1 6392 C8 2139 E4 2684 A1 3505 B7 4302 D6 7301 B8 9422 E2 9925 E8 2653 B1 6423 F9 2142 F6 2685 A1 3506 A5 4601 D1 7336 A9 9426 C5 9926 E4 2654 B1 6463 D9 2143 E6 2686 B1 3507 A5 4602 A5 7351 D1 9427 C5 9927 D2 2657 C1 6653 C1 2144 F5 2691 A1 3515 B5 4603 D3 7363 E7 9428 C6 9928 E2 2658 C1 6654 D1 2145 E5 2693 A1 3516 B4 4604 D6 7364 E6 9429 C6 9929 E4 2660 C1 7141 E4 2151 F5 2694 A1 3517 B6 4606 E7 7401 D9 9430 C6 9930 F6 2661 C1 7147 E5 2156 F2 3103 G1 3518 B6 5101 F2 7404 D9 9431 C6 9931 E4 2672 C1 7148 E5 2160 E1 3104 G4 3519 A6 5102 G2 7421 E9 9435 B6 9932 E3 2681 C1 7162 G5 2304 C9 3105 G3 3520 B6 5103 F2 7422 F9 9436 B6 9933 E2 3124 G5 7163 G5 2305 C9 3106 G3 3521 A6 5104 G4 7423 E9 9439 C7 9934 E4 3140 E4 7302 D9 2306 A8 3107 G3 3522 A6 5130 F4 7425 F8 9440 C7 9935 D6 3143 E4 7303 D9 2311 B9 3108 G3 3523 A7 5301 C8 7426 F8 9441 C7 9936 E5 3144 F5 7391 C8 2312 B9 3109 G2 3524 A6 5302 A9 7461 E7 9442 C7 9937 D5 3148 F5 7392 D8 2316 B9 3111 G6 3525 A6 5351 D1 7462 E9 9443 C7 9938 E6 3151 F5 7402 D8 2317 B8 3112 E3 3528 A7 5353 D1 7463 F9 9444 C7 9939 D5 3153 F5 7424 F9 2336 A9 3115 G5 3531 A7 5501 B6 7464 F9 9445 C7 9941 A4 3155 F6 7427 F9 2354 E1 3121 G4 3541 D5 5502 A5 7465 F8 9446 C7 9942 D5 3156 F6 7466 C9 2355 D2 3123 F3 3542 D3 5503 B5 7491 B8 9447 B7 9944 E5 3303 B9 7501 B6 2361 E7 3125 G5 3544 D4 5504 C5 7502 A5 9449 B7 9945 E6 3307 B8 7544 A7 2362 E6 3127 F1 3545 B4 5505 A5 7503 A6 9450 F8 9946 E5 3308 B8 7566 F8 2401 D8 3128 E1 3546 D5 5542 D4 7504 A6 9453 C8 9947 E5 3310 B9 7602 D2 2421 E8 3141 E4 3551 B3 5543 B3 7505 A7 9454 D8 9951 A5 3316 B9 7603 D2 2422 E8 3142 F5 3552 A3 5544 C3 7541 D3 9455 B8 9952 A1 3318 B8 7627 B6 2423 E8 3145 F5 3553 B3 5545 B4 7542 B3 9456 D9 9955 D1 3323 A9 7628 C6 2425 E8 3146 E5 3554 A3 5601 C4 7543 B3 9457 C8 3324 B8 7629 C6 2426 E8 3147 F5 3566 F8 5670 D1 7545 A7 9458 D8 3325 B8 7630 C6 2431 D9 3152 F5 3569 E6 5671 B2 7567 F7 9459 C9 3332 B8 7631 C5 2432 E9 3154 F5 3570 F7 5672 D2 7586 G8 9460 C9 3333 A9 7632 C5 2433 E9 3157 F6 3571 F7 6101 G3 7587 G7 9461 C7 3339 B8 7633 C5 2434 E9 3160 E2 3572 F7 6104 G4 7588 G7 9462 B9 3340 B8 7653 D1 2435 E9 3161 E1 3573 F6 6109 G4 7601 D2 9463 C9 3341 B8 7654 C1 2440 F9 3162 E1 3574 G7 6111 F6 7620 B6 9464 C7 3342 B8 2441 E9 3163 G4 3576 F7 6112 G5 7621 C6 9466 A9 3351 D1 2445 F9 3167 E2 3577 E6 6113 G5 7622 D6 9469 A8 3393 D8 2446 F9 3301 C9 3578 F7 6115 G5 7651 C1 9476 C7 3394 D8 2456 F8 3302 B9 3579 F7 6116 F5 7652 B1 9477 C8 3395 D8 2461 F7 3304 C9 3580 F7 6125 G5 7671 C1 9478 B9 3396 D8 2463 F9 3305 C9 3581 B5 6131 E3 7672 C1 9486 C9 3401 D8 2491 B8 3306 C9 3582 F7 6132 E5 7673 C2 9487 C8 3402 D8 2501 B7 3309 C9 3586 F8 6133 E3 7674 A1 9488 C8 3403 E9 2502 A7 3311 B9 3587 G8 6134 E4 7675 D2 9491 C8 3405 C8 2503 A7 3312 A9 3588 F8 6135 E3 8001 C8 9493 C8 3423 E8 2506 B4 3313 A9 3589 G8 6137 E4 8002 A8 9501 C8 3425 E7 2507 B5 3314 A8 3590 G8 6139 F5 8003 E6 9502 D8 3429 F9 2508 B4 3315 A8 3591 G7 6140 E5 8004 A8 9504 C8 3430 F9 2509 A4 3317 D8 3592 G7 6144 F5 8101 G3 9505 E4 3431 E9 2515 B5 3319 A9 3593 G7 6145 E5 8102 F3 9506 D3 3434 E9 2516 B6 3320 A8 3594 B7 6152 F5 8103 F2 9508 D9 3444 E9 2517 A6 3321 A8 3601 D3 6161 G5 8104 G2 9509 D9 3445 E9 2518 A7 3322 B8 3602 C3 6302 A8 8105 G2 9511 E7 3446 E9 2519 A6 3326 D8 3603 C3 6421 F9 8106 F5 9512 E7 3451 F9 2520 A6 3327 C8 3604 C3 6422 E8 8301 A9 9513 E8 3457 F8 2542 D3 3328 A9 3605 D3 6424 E9 8302 F9 9514 D8 3464 E7 2543 D4 3329 A9 3606 C3 6426 E9 9101 E5 9515 D8 3467 D9 2544 D4 3330 C9 3607 C3 6462 E7 9102 G2 9516 D8 3491 B8 2551 B3 3331 C9 3608 D2 6464 F8 9103 G2 9517 D8 3492 B8 2552 A3 3334 A8 3609 C2 6491 C8 9104 G3 9518 E7 3494 B8 2553 C4 3335 A8 3611 D2 6492 C8 9105 F2 9519 E7 3527 A7 2554 C4 3337 A9 3613 E2 6501 B6 9106 G2 9521 D8 3529 A6 2555 C4 3338 A9 3615 D2 6502 B6 9111 F5 9522 D8 3530 A7 2566 F8 3343 B9 3616 D2 6503 A7 9112 G4 9523 D8 3555 A7 2567 E7 3352 D1 3617 A2 6506 A5 9113 F5 9525 D7 3556 A7 2568 F7 3353 E1 3621 B6 6507 B5 9114 G4 9526 D7 3610 B1 2569 F7 3354 D7 3623 C6 6508 A4 9131 E5 9529 D6 3612 D2 2573 G7 3355 D7 3625 C6 6509 A4 9132 E5 9531 B7 3614 D2 2576 F7 3397 C8 3627 C6 6510 A3 9133 D7 9532 A7 3618 F5 2577 E7 3398 C8 3629 C6 6515 B4 9135 E4 9533 A8 3620 B6 2578 F7 3404 E8 3631 C5 6518 A3 9141 E5 9534 A8 3622 C6 � Go to cover page Forward Back 26 109P2 GS3 CM25 Power Supply Schematic Diagram Control panel C C12 C11 C10 C9 C8 C7 C6 C5 C4 C3 C2 C1 � Go to cover page Forward Back 109P2 GS3 CM25 Driver Schematic Diagram PCB(D) D 27 1201 C1 1202 B1 1203 A4 1204 A3 1205 A2 1206 A1 2201 B4 2202 B1 2203 C1 2204 C2 2205 B1 2206 B1 2209 B1 2211 B1 2212 B1 2213 B1 2229 C1 2230 C4 2231 B3 2232 B3 2233 B3 2234 C3 2235 C3 2236 C3 2237 C1 2238 C1 2239 B1 2240 B3 2241 B4 2242 B4 2243 B3 2244 B3 2245 B3 2246 B3 2247 B2 2248 A1 2249 A4 2250 A2 2251 A1 2252 A1 2253 A4 2254 A4 2255 A4 2256 A3 2257 A3 2258 A3 2259 A3 2260 A3 2261 A2 2262 A2 2263 A1 2264 A1 2265 A1 2266 A1 3201 B1 3202 B2 3203 C2 3204 B2 3205 B2 3206 B2 3207 B2 3208 B1 3209 C1 3210 B1 3211 C2 3212 C1 3213 C1 3214 C1 3215 C2 3216 C1 3217 B1 3218 B1 3219 B1 3221 B1 3222 B1 3223 B2 3224 B2 3225 B1 3230 C2 3231 C2 3232 C2 3233 C2 3234 C3 3235 C4 3236 C3 3237 C3 3238 B3 3239 B3 3241 B4 3242 B4 3243 B3 3244 B3 3245 B3 3246 B2 3247 B2 3248 A2 3249 A4 3250 A4 3251 A4 3252 A4 3253 A4 3254 A4 3255 A4 3256 A4 3257 A3 3258 A3 3259 A3 3260 A3 3261 A3 3262 A3 3263 A2 3264 A3 3265 A2 3266 A2 3267 A2 3268 A2 3269 A1 3270 A1 3271 A1 3272 A1 3273 A1 3274 A1 3275 A1 3276 A1 3277 A4 3278 A4 3279 A4 3280 A4 3281 A4 3282 A4 3283 A3 3284 A3 3285 A3 3286 A3 3287 A3 3288 A3 3289 A2 3290 A2 3291 A2 3292 A1 3293 A1 3294 A1 3295 A1 3296 A1 3297 A1 4201 A4 4202 A3 4203 A2 4204 A1 6201 B2 6202 A1 6203 C3 6204 C3 6205 C3 6206 C3 6207 C1 6208 C1 7201 B4 7202 C1 7203 B1 7204 C3 7205 B3 7206 A4 7207 A3 7208 A2 7209 A1 9201 C4 9203 C1 9204 B1 9205 C4 9206 C2 9207 C1 9208 B1 9209 B1 9210 A2 9211 A3 9212 B1 9213 C4 9214 A1 9215 A1 � Go to cover page Forward Back 28 109P2 GS3 CM25 E Power Down Diagram MHR Diagram PCB(E) � Go to cover page Forward Back Repair Tips Repair Tips 0. Warning 1. Servicing of SMDs (Surface Mounted Devices) All ICs and many other semi-conductors are susceptible to electrostatic discharges (ESD). Careless handling during repair can reduce life drastically. When repairing, make sure that you are connected with the same potential as the mass of the unit via a wrist wrap with resistance. Keep components and tools also at the same potential ! 1.1 General cautions on handling and storage - Oxidation on the terminals of SMDs results in poor soldering. Do not handle SMDs with bare hands. - Avoid using storage places that are sensitive to oxidation such as places with sulphur or chlorine gas, direct sunlight, high temperatures or a high degree of humidity. The capacitance or resistance value of the SMDs may be affected by this. - Rough handling of circuit boards containing SMDs may cause damage to the components as well as the circuit boards. Circuit boards containing SMDs should never be bent or flexed. Different circuit board materials expand and contract at different rates when heated or cooled and the components and/or solder connections may be damaged due to the stress. Never rub or scrape chip components as this may cause the value of the component to change. Similarly, do not slide the circuit board across any surface. 1.2 Removal of SMDs - Heat the solder (for 2-3 seconds) at each terminal of the chip. By means of litz wire and a slight horizontal force, small components can be removed with the soldering iron. They can also be removed with a solder sucker (see Fig. 1A) - While holding the SMD with a pair of tweezers, take it off gently using the soldering iron's heat applied to each terminal (see Fig. 1 B). - Remove the excess solder on the solder lands by means of litz wire or a solder sucker (see Fig. 1C). 1.3 Caution on removal - When handling the soldering.iron. use suitable pressure and be careful. - When removing the chip, do not use undue force with the pair of tweezers. - The soldering iron to be used (approx. 30 W) should 1.4 Attachment of SMDs - Locate the SMD on the solder lands by means of tweezers and preferably be equipped with a thermal control (soldering temperature: 225 to 250 C). - The chip, once removed, must never be reused. o solder the component on one side. Ensure that the component is Positioned correctly on the solder lands (see Fig.2A). - Next complete the soldering of the terminals of the component (see Fig. 2B). - When soldering the SMD terminals, do not touch them directly with the soldering iron. The soldering should be done as quickly as possible, care must be taken to avoid damage to the terminals of the SMDs themselves. - Keep the SMD's body in contact with the printed board when soldering. - The soldering iron to be used (approx. 30 W ) should preferably be equipped with a thermal control (soldering temperature: 225 to 250 C). - Soldering should not be done outside the solder land. - Soldering flux (of rosin) may be used, but should not be acidic. - After soldering, let the SMD cool down gradually at room temperature. - The quantity of solder must be proportional to the size of the solder land. If the quantity is too great, the SMD might crack or the solder lands might be torn loose from the printed board (see Fig. 3). 2. Caution when attaching SMDs o SOLDERING IRON RIGHT Fig. 3 Examples DISMOUNTING VACUUM PISTON 4822 395 10159 SOLDERING IRON e.g. WELLER SOLDER TIP PT -H7 SOLDERING IRON SOLDER WICK 4822 321 40042 SOLDERING IRON SOLDER WICK e.g. A PAIR OF TWEEZERS HEATING HEATING Fig. 1 A B C e.g. A PAIR OF TWEEZERS SOLDER 0.5 - 0.8 mm SOLDER 0.5 - 0.8 mm SOLDERING IRON SOLDERING TIME < 3 sec/side SOLDERING IRON PRESURE PRESURE MOUNTING Fig. 2 B A 26 29 109P2 GS3 CM25 � Go to cover page Forward Back 30 109P2 GS3 CM25 Exploded View 1165 OPTION 3 49 1 2 1051 1160 1161 1055 3138 107 99270 Pedestal ASSY 3138 127 50760 FRONT CABINET ASSY 8238 274 39731 M41BLRY 22X21 0.24MM 3138 104 51230 SCREW COVER 3138 127 50770 BACK COVER ASSY 3138 178 53370 VIDEO PCB ASSY 3138 178 54300 D-COIL & -SHIELD 3138 178 54360 109P2-MAIN PCB ASSY 3138 178 53330 109P2-MHR PCB ASSY � Go to cover page Forward Back 31 109P2 GS3 CM25 Recommended Parts List Model :109P20/00C Parts indicated on exploded view 1 3138 127 50760 FRONT CABINET ASSY 2 3138 107 50770 BACK COVER ASSY 3 3138 107 99270 PEDESTAL ASSY 43 3138 104 49440 BACK COVER 53 3138 104 49460 SWIVEL 1051 8238 274 39731 CRT 19"M46LRY22X21 0.24MM 1055 3138 178 54301 D-COIL & F-SHIELD ASSY 1160 3138 178 54361 109P2 MAIN PCB ASSY 1161 3138 178 53371 109P2 VIDEO PCB ASSY 1162 3138 178 04701 TERMINAL PCB ASSY 1163 3138 178 53381 109P2 CONTROL PCB ASSY 1164 3138 178 06951 DRIVE PCB ASSY 1165 3138 178 53330 109P2-MHR PCB ASSY 1166 3138 178 50321 POWER DOWN PCB ASSY 601 3138 117 02651 E-D.F.U ASSY (CD+ROM+Quick Start Guide) 602 3138 117 02661 E-D.F.U(CD-ROM Disc) 178 3138 106 58051 SETTING UP GUIDE 450 3138 106 59311 CARTON 451 3138 106 56792 CUSHION-BOTTOM 452 3138 106 56801 CUSHION-TOP 454 3138 106 56651 PE BAG 1053 2438 070 98118 MAINS CORD 1054 3138 168 74451 I/F CABLE 1103 2422 086 00208 FUSE T4AH/ 250V 1265 3138 178 53391 EEPROM ASSYGS109P2(7336) 5130 3138 168 74281 POWER TRANSFORMER 5503 3138 168 73551 LINEARITY COIL(54A-9050H) 5504 3138 168 73541 LINEARITY COIL(54A-9049H) 5601 3138 128 74411 DAF TRANSFORMER 5671 3138 168 76541 L.O.T 7111 3198 020 43011 TRANS BF422 7121 9322 145 76682 ICSTRF6656(LF1352) 7130 9322 140 14667 PHOTOCOUPLER TCET1103G 7143 9322 092 00687 IC L4940V5 3P 7144 9337 739 70687 MOSFET IR640 7146 9340 039 60126 TRANS BSN254A 7155 9337 711 00686 IC TL431CLPRP 3P 7301 3138 178 54161 109P2-OTP CPU ASSY 7364 9339 208 10682 IC L7808CV 3P 7404 9332 826 60652 IC HEF4053BP 16P 7421 9352 623 32112 IC TDA4856/V2 32P 7491 9322 098 98682 IC ST24LCBB6 8P 7502 9322 144 42671 TRANS 2SC5445 7622 9322 145 62667 TRANS LA5058 44 3138 104 49470 BASE-PEDESTA 46 3138 104 51180 KNOB OSD 47 3138 104 54050 KNOB POWER � Go to cover page Forward Back 32 109P2 GS3 CM25 Spare Parts List Model :109P20/00C Item code number Description 0001 313812750760 FRONT CABINET ASSY (109P2) 0002 313812750770 BACK COVER ASSY (109P2) 0003 313810799270 PEDESTAL ASSY 0004 313812750780 KNOB ASSY (109P2) 0043 313810449440 REAR-COVER 0044 313810449470 BASE 0046 313810451180 KNOB-OSD 0047 313810454050 KNOB-POWER 0048 313810450672 LENS-POWER 0049 313810451230 SCREW COVER 0053 313810449460 SWIVEL 0151 313810632613 P.E. BAG 0153 313810658051 P.E. BAG-E-D.F.U. 0178 313810658051 SETTING UP GUIDE 1051 823827439731 CRT 19" M46LRY 22X21 0.24MM 1053 243807098118 MAINS CORD 1054 313816874451 I/F CABLE 1059 332214489801 SPOILER 1061 313816875661 DEGASSING COIL 1102 243812800107 POWER SWITCH 1103 242208600208 FUSE T4AH 250V 1130 243813200056 RELAY - OMI-SS-212DM 1160 313817854361 109P2-M MAIN PCB ASSY 5430 1161 313817853371 109P2-VIDEO PCB ASSY 1162 313817804701 TERMINAL PCB ASSY 1163 313817853381 109P2-CONTROL PCB ASSY 5230 1164 313817806951 DRIVE PCB ASSY 5252 1165 313817853330 109P2 MHR PCB ASSY(OPTION) 1166 313817850321 POWER DOWN PCB ASSY 1265 313817853391 109P2-M EEPROM ASSY(7336-M24C1 1272 313817806391 VIDEO IC ASSY LM2402(7705) 1301 243854300064 CRYSTAL-12MHZ 2001 203803550227 ELECAP SS 220U 10V 6*7T 2002 203803550312 ELCAP SS 220UF 16V 2003 203803500037 ELCAP SM 16V 47U PM20 2E T 2004 203803500037 ELCAP SM 16V 47U PM20 2E T 2005 203803500037 ELCAP SM 16V 47U PM20 2E T 2007 203803500037 ELCAP SM 16V 47U PM20 2E T 2008 223891015649 CER2 0805 X7R 25V 100N CO 2010 223891015649 CER2 0805 X7R 25V 100N CO 2011 203803500037 ELCAP SM 16V 47U PM20 2E T 2013 203803500037 ELCAP SM 16V 47U PM20 2E T 2017 223891015649 CER2 0805 X7R 25V 100N CO 2018 223886115109 CAP 10PF 0805 SMD 2019 223886115109 CAP 10PF 0805 SMD 2020 223886115109 CAP 10PF 0805 SMD 0450 313810659311 CARTON 0451 313810656792 CUSHION - BOTTOM 0452 313810656801 CUSHION - TOP 0454 313810656651 PE BAG 0601 313811702651 E-D.F.U ASSY-W/O V/E 0602 313811702661 E-D.F.U-W/O V/E Item Code Number Description 2031 223886115229 CAP 22PF 0805 SMD NPO 2032 223886115229 CAP 22PF 0805 SMD NPO 2033 223886115229 CAP 22PF 0805 SMD NPO 2034 223886115229 CAP 22PF 0805 SMD NPO 2035 223891015649 CER2 0805 X7R 25V 100N CO 2036 223891015649 CER2 0805 X7R 25V 100N CO 2102 202030790011 ACROSS LINE CAP 250V 220N PM10 2103 203803500042 ELCAP LXK 400V S 330U PM 20 2104 823827437251 CAP MEF 400V 33N 2111 203803155101 ELCAP S 35V 100UF PM20 2E 2112 203803550202 ELCAP SH 250V S 1U PM20 A 2115 202055890542 CER2 DC RR 1KV S 100P PM10 A 2116 203803145479 ELCAP VT 25V 47UF PM20 2E T 2121 202055890555 CCAP DC RR 1KV S 470P K A 2122 202055890557 CERC RR 1KVDC 1N PM10 2123 223858015636 CER2 0805 X7R 50V 10N PM10 R 2124 202055790151 CERC DC 500V 1N0 PM10 2125 223858015641 SMD C0805 22N 63V PM10 X710 R 2127 222234741473 POLCAP S 250V 47N PM10 6E 2128 202055490139 CERSAF NSB 250V S 4N7 PM20 B 2129 202055490127 CERSAF NSA 250V S 2N2 PM20 B 2130 202055490149 CAP Y ECKWNA 250V 3N3 2131 203803500081 ELCAP SX 250V S 100U PM20 B 2133 203803500099 ELCAP SX 100V S 220U PM20 B 2134 203803500079 ELCAP SX 25V S 2200U PM20 B 2135 203803500078 ELCAP SX 25V S 1000U PM20 B 2137 203803500078 ELCAP SX 25V S 1000U PM20 B 2139 203803500056 ELCAP 2200UF 16V SX PM20 2142 203801700325 ELCAP VZ 10V S 4700U PM20 B 2143 203801700325 ELCAP VZ 10V S 4700U PM20 B 2144 203803195005 ELCAP S 160V 1UF PM20 2E T 2145 202055890542 CER2 DC RR 1KV S 100P PM10 A 2151 203803165478 ELCAP 4UF7 50V PM20 VT A 2154 223891015645 CAP 47NF SMD 0805 X7R 2155 223886115471 CMC 0805 NPO 470P 50V J 2156 202055490149 CAP Y ECKWNA 250V 3N3 2160 203803452101 ELCAP S 10V 100UF PM20 2E T 2161 223891015649 CER2 0805 X7R 25V 100N CO 2162 223891015649 CER2 0805 X7R 25V 100N CO 2192 203830200203 MEF CAP 630V 47N 6E PM10 2201 225232512103 CERC CAP 50V 10N X7R 2E 2202 203803454101 ELCAP S 25V 100UF PM20 2E 2209 203803454101 ELCAP S 25V 100UF PM20 2E 2213 225232512103 CERC CAP 50V 10N X7R 2E 2229 225232512103 CERC CAP 50V 10N X7R 2E 2230 203803453229 ELCAP S 16V 22UF PM20 2E 2231 203803453229 ELCAP S 16V 22UF PM20 2E 2234 203803453229 ELCAP S 16V 22UF PM20 2E 2239 203803142471 ELCAP 470UF 25V PM20 2E 105C B 2240 203803453229 ELCAP S 16V 22UF PM20 2E 2248 203803453229 ELCAP S 16V 22UF PM20 2E 2249 203803424471 ELCAP S 25V 470UF PM20 2E 2250 203803424471 ELCAP S 25V 470UF PM20 2E 2251 203803424471 ELCAP S 25V 470UF PM20 2E 2252 203803423471 ELCAP S 16V 470UF PM20 2E B 2302 223858016614 CER2 0805 X7R 50V 1N PM10 2304 203830250095 MEF CAP 100V 100N PM10 2E 2306 203803456109 ELCAP S 50V 10UF PM20 2E 2309 223886115339 CAP 33PF 0805 SMD NPO 2310 223886115339 CAP 33PF 0805 SMD NPO 2311 203803550227 ELECAP SS 220U 10V 6*7T 2312 203830250212 POLCAP 100V 100N PM5 2E T 2313 223886115229 CAP 22PF 0805 SMD NPO 2314 223886115229 CAP 22PF 0805 SMD NPO 2315 223858016614 CER2 0805 X7R 50V 1N PM10 2316 203803550227 ELECAP SS 220U 10V 6*7T 2317 203803456109 ELCAP S 50V 10UF PM20 2E 2336 203830250095 MEF CAP 100V 100N PM10 2E 2337 223886115229 CAP 22PF 0805 SMD NPO 2021 223886115109 CAP 10PF 0805 SMD 2023 203803550227 ELECAP SS 220U 10V 6*7T 2025 203803550227 ELECAP SS 220U 10V 6*7T 2027 203803550227 ELECAP SS 220U 10V 6*7T � Go to cover page Forward Back 33 109P2 GS3 CM25 Spare Parts List 2338 223886115229 CAP 22PF 0805 SMD NPO 2361 203803135331 ELCAP S 16V 330UF PM20 2E T 2362 203803135101 ELCAP VT 16V 100UF PM20 2E T 2391 223891015649 CER2 0805 X7R 25V 100N CO 2392 223886115101 CER2 0805 NPO 50V 100P 2401 203830250095 MEF CAP 100V 100N PM10 2E 2421 203830250095 MEF CAP 100V 100N PM10 2E 2422 203830250121 MEF CAP 100V 150N 2E PM10 2423 202055290607 CERC DC NPO 50V 220P PM5 2E T 2424 223891015649 CER2 0805 X7R 25V 100N CO 2425 203803453102 ELCAP S 16V 1000UF PM20 T 2426 202055290594 CERC DC NPO 50V 22P PM5 2E T 2431 203830250212 POLCAP 100V 100N PM5 2E T 2432 203830150186 PPN 100V 8N2 PM5 T 2433 203830250218 MEF CAP 10N 100V PM2 2E 2434 203830150157 CAP PP PPN 100V S 5N6 PM2 A 2435 203830150186 PPN 100V 8N2 PM5 T 2441 203830150191 PPN 100V 3N3 PM2 T 2442 223886115471 CMC 0805 NPO 470P 50V J 2443 223891015645 CAP 47NF SMD 0805 X7R 2444 223891015645 CAP 47NF SMD 0805 X7R 2445 203803453479 ECAP S 16V 47UF M 2E T 2446 203830250099 POLCAP 100V 470N PM10 2E 2456 203803453479 ECAP S 16V 47UF M 2E T 2461 202030190148 PPN CAP 220N 250V PM5 9E 2462 223886115221 MLCC 0850 NPO 220PF J 4B 9 2463 203803453479 ECAP S 16V 47UF M 2E T 2464 223858016624 SMD0805X7R 5N6 50V +/-10% 2491 203830250095 MEF CAP 100V 100N PM10 2E 2492 223886115101 CER2 0805 NPO 50V 100P 2493 223886115101 CER2 0805 NPO 50V 100P 2501 203803195005 ELCAP S 160V 1UF PM20 2E T 2502 203802650007 NON-POLAR CAP 160V 1U C 2503 203830250095 MEF CAP 100V 100N PM10 2E 2506 202055890561 CERC CAP RR 2KV 220P PM10 B 2507 202055890561 CERC CAP RR 2KV 220P PM10 B 2508 203830100404 PPNS CAP 2KV 4N7 PM5 B 2515 202055890557 CERC RR 1KVDC 1N PM10 2516 203830250099 POLCAP 100V 470N PM10 2E 2518 203830250095 MEF CAP 100V 100N PM10 2E 2519 203830250095 MEF CAP 100V 100N PM10 2E 2520 203830250095 MEF CAP 100V 100N PM10 2E 2542 203830200155 MEF CAP 250V 100N PM10 2543 203803500048 ELCAP SEK 250V S 100U PM20 B 2544 202055890561 CERC CAP RR 2KV 220P PM10 B 2545 223891015649 CER2 0805 X7R 25V 100N CO 2546 223891015649 CER2 0805 X7R 25V 100N CO 2551 203803145479 ELCAP VT 25V 47UF PM20 2E T 2552 203803145479 ELCAP VT 25V 47UF PM20 2E T 2553 203830100164 CAP PP PPN 250V S 150N PM5 B 2554 203830100412 PPN CAP 68N 250V PM5 8E 2566 203803165109 ELCAP VT 50V 10UF PM20 2E 2567 203803142471 ELCAP 470UF 25V PM20 2E 105C B 2568 203803455101 ELCAP S 35V 100UF PM20 2E 2569 202055290607 CERC DC NPO 50V 220P PM5 2E T 2576 203830250093 MEF CAP 100V 22N PM10 2E 2577 203803142471 ELCAP 470UF 25V PM20 2E 105C B 2578 203830250095 MEF CAP 100V 100N PM10 2E 2579 203830250099 POLCAP 100V 470N PM10 2E 2586 203830250212 POLCAP 100V 100N PM5 2E T 2587 203830250095 MEF CAP 100V 100N PM10 2E 2588 203830250095 MEF CAP 100V 100N PM10 2E 2589 203830250095 MEF CAP 100V 100N PM10 2E 2601 202055890604 CERC CAP 100P 2KV RR TYPE 2602 202055890604 CERC CAP 100P 2KV RR TYPE 2603 202055890557 CERC RR 1KVDC 1N PM10 2604 202055890604 CERC CAP 100P 2KV RR TYPE 2605 202055890561 CERC CAP RR 2KV 220P PM10 B 2608 223555900099 CERC CAP 2KV 10N PM20 4E 2611 203803454479 ELCAP S 25V 47UF PM20 2E T 2612 223891015649 CER2 0805 X7R 25V 100N CO 2613 203803456479 ELCAP S 50V 47UF PM20 2E T 2621 203830100208 CAP PP PPN 250V S 47N PM5 B 2622 203830100184 CAP PP PPN 250V S 68N PM5 B 2623 203830100305 MPS CAP 180N 250V PM5 2624 203830100331 MPS CAP 360N 250V PM5 7E 2625 203830100222 MPS CAP 820N 250V PM5 8E Item Code Number Description 2626 203830100217 CAP MPS 1U5 250V PM5 B 2651 203803456108 ELCAP S 50V 1UF PM20 2E T 2652 223858016616 CER2 0805 X7R 63V 1N5 PM10 R 2653 223858016621 MLCC 0805 X7R 3N3 K 4B 9 2655 203830150151 CAP PP PPN 100V S 10N PM2 B 2656 203803145221 ELCAP S 25V 220UF PM20 2E T 2657 223858016615 CER2 0805 X7R 63V 1N2 PM10 R 2658 223878019858 CER2 0805 Y5V 16V 470N P8020 R 2659 203803454479 ELCAP S 25V 47UF PM20 2E T 2660 223878019858 CER2 0805 Y5V 16V 470N P8020 R 2661 223878019858 CER2 0805 Y5V 16V 470N P8020 R 2671 203803192003 ELCAP S 250V 33UF PM20 2E 2672 223891015649 CER2 0805 X7R 25V 100N CO 2673 202055890562 CERC RB 2KVDC 330PF 2681 223858016618 CAP 2NF2 0805 SMD X7R T 2682 203803500081 ELCAP SX 250V S 100U PM20 B 2683 203830100174 CAP PP PPN 630V S 4N7 PM5 A 2684 222234741473 POLCAP S 250V 47N PM10 6E 2685 203803453479 ECAP S 16V 47UF M 2E T 2686 202055890557 CERC RR 1KVDC 1N PM10 2691 222234741473 POLCAP S 250V 47N PM10 6E 2693 203830200226 CAP MPOL 100V S 1U8 PM5 B 2694 203830250212 POLCAP 100V 100N PM5 2E T 2701 223886115478 SMD 0805 NPO 4P7 50V 0.25P 2702 223858016627 CER2 0805 X7R 50V 10N PM10 R 2704 203803522801 ECAP NP 1U 160V 105C NK 2705 203803550202 ELCAP SH 250V S 1U PM20 A 2706 242254944346 SPARK GAP DSP-201m 2707 223891015649 CER2 0805 X7R 25V 100N CO 2708 223891015649 CER2 0805 X7R 25V 100N CO 2709 223891015649 CER2 0805 X7R 25V 100N CO 2710 223886115279 CAP 27PF 0805 SMD NPO 2720 222286112479 MLCC 0805 NPO 50V 47P COL R 2721 223886115478 SMD 0805 NPO 4P7 50V 0.25P 2722 223858016627 CER2 0805 X7R 50V 10N PM10 R 2724 203803522801 ECAP NP 1U 160V 105C NK 2725 203803550202 ELCAP SH 250V S 1U PM20 A 2726 242254944346 SPARK GAP DSP-201m 2727 223891015649 CER2 0805 X7R 25V 100N CO 2732 232273091002 RST SM 0805 JUMP. MAX 0R05 T 2736 222291019856 CER2 0805 Y5V 25V 330N P8020 R 2740 223886115229 CAP 22PF 0805 SMD NPO 2741 223886115478 SMD 0805 NPO 4P7 50V 0.25P 2742 223858016627 CER2 0805 X7R 50V 10N PM10 R 2744 203803522801 ECAP NP 1U 160V 105C NK 2745 203803550202 ELCAP SH 250V S 1U PM20 A 2746 242254944346 SPARK GAP DSP-201m 2748 203803145479 ELCAP VT 25V 47UF PM20 2E T 2749 223891015649 CER2 0805 X7R 25V 100N CO 2750 223891015649 CER2 0805 X7R 25V 100N CO 2751 223891015649 CER2 0805 X7R 25V 100N CO 2752 203803182479 ELCAP VT 100V S 47U PM20 B 2753 203803550202 ELCAP SH 250V S 1U PM20 A 2760 223891015649 CER2 0805 X7R 25V 100N CO 2761 223555900099 CERC CAP 2KV 10N PM20 4E 2762 225260214416 CERC CAP DC 2KV 470P PM10 X7R 2763 202055790151 CERC DC 500V 1N0 PM10 2764 225261108216 DISC CAP Y5P 1KV 220PF K 2E T 2765 225260214216 CERCAP DC 2KV 220P K X7R T 2770 203803165109 ELCAP VT 50V 10UF PM20 2E 2771 223891015649 CER2 0805 X7R 25V 100N CO 2772 203803145479 ELCAP VT 25V 47UF PM20 2E T 2773 223891015649 CER2 0805 X7R 25V 100N CO 2774 223891015649 CER2 0805 X7R 25V 100N CO 2775 203803135331 ELCAP S 16V 330UF PM20 2E T 2776 223891015649 CER2 0805 X7R 25V 100N CO 2777 203803145479 ELCAP VT 25V 47UF PM20 2E T 2778 223891015649 CER2 0805 X7R 25V 100N CO 2779 203803182479 ELCAP VT 100V S 47U PM20 B 2780 203830250095 MEF CAP 100V 100N PM10 2E 2781 203803550202 ELCAP SH 250V S 1U PM20 A 2782 203830250166 MEF CAP 400V 10N PM10 2E T 2783 223886115229 CAP 22PF 0805 SMD NPO 2784 223886115229 CAP 22PF 0805 SMD NPO 2785 223886115229 CAP 22PF 0805 SMD NPO � Go to cover page Forward Back 34 109P2 GS3 CM25 Spare Parts List Item Code Number Description 2786 223886115229 CAP 22PF 0805 SMD NPO 2787 223891015649 CER2 0805 X7R 25V 100N CO 2788 223891015649 CER2 0805 X7R 25V 100N CO 2789 223886115101 CER2 0805 NPO 50V 100P 2790 223886115101 CER2 0805 NPO 50V 100P 2791 203803135101 ELCAP VT 16V 100UF PM20 2E T 2792 223858016623 MLCC 0805 X7R 4N7F K 4B 9 2793 223886115101 CER2 0805 NPO 50V 100P 2794 223886115221 MLCC 0850 NPO 220PF J 4B 9 2795 223858015641 SMD C0805 22N 63V PM10 X710 R 2796 223886115221 MLCC 0850 NPO 220PF J 4B 9 2798 203803135101 ELCAP VT 16V 100UF PM20 2E T 2799 223891015649 CER2 0805 X7R 25V 100N CO 2801 223858016627 CER2 0805 X7R 50V 10N PM10 R 2802 223886115101 CER2 0805 NPO 50V 100P 2803 223891015649 CER2 0805 X7R 25V 100N CO 2804 223886115181 MLCC 0805 NPO 180PF J 4B 9 2805 223891015649 CER2 0805 X7R 25V 100N CO 2806 223891015649 CER2 0805 X7R 25V 100N CO 2807 223891015649 CER2 0805 X7R 25V 100N CO 2811 203803550202 ELCAP SH 250V S 1U PM20 A 2812 223858016614 CER2 0805 X7R 50V 1N PM10 2813 223858016621 MLCC 0805 X7R 3N3 K 4B 9 2814 223891015649 CER2 0805 X7R 25V 100N CO 2815 223891015649 CER2 0805 X7R 25V 100N CO 2821 223858016614 CER2 0805 X7R 50V 1N PM10 2822 223858016621 MLCC 0805 X7R 3N3 K 4B 9 2831 223858016614 CER2 0805 X7R 50V 1N PM10 2832 223858016621 MLCC 0805 X7R 3N3 K 4B 9 2891 223891015649 CER2 0805 X7R 25V 100N CO 2892 223891015649 CER2 0805 X7R 25V 100N CO 2893 223891015649 CER2 0805 X7R 25V 100N CO 2894 223858016627 CER2 0805 X7R 50V 10N PM10 R 2895 223858016627 CER2 0805 X7R 50V 10N PM10 R 3001 232273061222 RST SM 0805 RC11 2K2 PM5 R 3004 232273061222 RST SM 0805 RC11 2K2 PM5 R 3006 232273061479 RES 47R 0805 SMD RC-11 T 3007 232273467509 RST SM 0805 RC11 75R PM1 T 3008 232273061479 RES 47R 0805 SMD RC-11 T 3009 232273467509 RST SM 0805 RC11 75R PM1 T 3010 232273061479 RES 47R 0805 SMD RC-11 T 3011 232273467509 RST SM 0805 RC11 75R PM1 T 3012 232273061471 RST SM 0805 RC11 470R PM5 R 3013 232273061471 RST SM 0805 RC11 470R PM5 R 3014 232273061471 RST SM 0805 RC11 470R PM5 R 3015 232273061471 RST SM 0805 RC11 470R PM5 R 3016 232273061479 RES 47R 0805 SMD RC-11 T 3017 232273467509 RST SM 0805 RC11 75R PM1 T 3018 232273061222 RST SM 0805 RC11 2K2 PM5 R 3019 232273061479 RES 47R 0805 SMD RC-11 T 3020 232273467509 RST SM 0805 RC11 75R PM1 T 3021 232273061479 RES 47R 0805 SMD RC-11 T 3022 232273467509 RST SM 0805 RC11 75R PM1 T 3023 232273061222 RST SM 0805 RC11 2K2 PM5 R 3103 213866000033 NTC THERMISTOR 8R PM15 SCK-081 3104 213810500337 1W 100K RSS (T) 3105 213810500337 1W 100K RSS (T) 3106 212010592436 MET FLM RSS 3W 47K PM5 3107 213811612204 RST MFLM MF50S A 220K PM1 A 3108 213811612704 RST MFLM MF50S A 270K PM1 A 3109 213811612203 RST MFLM MF50S A 22K PM1 A 3111 213810500332 RST 5W 22K PM5 3112 213811614703 RST MFLM MF50S A 47K PM1 A 3115 213811613302 RST MFLM MF50S A 3K3 PM1 A 3121 213811611002 RST MFLM MF50S A 1K PM1 A 3123 213810500338 5W 0.12R MPR 6E 3124 232273061103 RES 10K RC-11 SMD 0805 T 3125 213811615602 RST MFLM MF50S A 5K6 PM1 A 3128 232266296758 DEGAUSSING PTC THERMISTOR B 3140 232273061102 RST SMC 0805 RC11 1K PM5 T 3141 213811273331 CARBRST FLM CR25 330R PM5 T 3142 212010592383 MTL RES 2W 2R2 RSS .M Item Code Number Description 3143 232273091002 RST SM 0805 JUMP. MAX 0R05 T 3144 232273061105 RES 1M RC-11 SMD 0805 T 3145 212010592169 RES 2W 12K 3146 213810113103 RST CRB CR12 A 10K PM5 A 3147 212266200119 POLYSWITCH RXE065-AP 3148 232273061682 RES 6K8 0805 SMD 3151 232273061102 RST SMC 0805 RC11 1K PM5 T 3152 213811273102 CARBRST FLM CR25 1K0 PM5 5 3153 232273061101 RST SM 0805 RC11 100R PM5 R 3154 213811613304 RST MFLM MF50S A 330K PM1 A 3155 232273061105 RES 1M RC-11 SMD 0805 T 3156 232273061472 RST SM 0805 RC11 4K7 PM5 R 3157 213836500081 RTRM CER LIN 1K H VG067TL1 B 3160 213811614709 RST MFLM MF50S A 47R PM1 A 3161 213810113223 RST CRB CR12 A 22K PM5 A 3162 213810113103 RST CRB CR12 A 10K PM5 A 3163 213811612709 RST MFLM MF50S A 27R PM1 A 3167 213811611004 RST MFLM MF50S A 100K PM1 A 3191 213810113101 RST CRB CR12 A 100R PM5 A 3192 213810113474 RST CRB CR12 A 470K PM5 A 3193 232224213225 METGLAZ RST A VR37 2M2 PM5 T 3201 212010592397 MET FLM RST RSS 3W 120R PM5 8E 3204 213811612402 RST MFLM MF50S A 2K4 PM1 A 3205 213811619109 RST MFLM MF50S A 91R PM1 A 3206 213811612402 RST MFLM MF50S A 2K4 PM1 A 3207 213811611201 RST MFLM MF50S A 120R PM1 A 3210 213811611002 RST MFLM MF50S A 1K PM1 A 3217 213811612103 RST MFLM MF50S A 21K PM1 A 3218 213811611204 RST MFLM MF50S A 120K PM1 A 3219 213811612103 RST MFLM MF50S A 21K PM1 A 3221 213811611204 RST MFLM MF50S A 120K PM1 A 3222 213811611503 RST MFLM MF50S A 15K PM1 A 3223 213811611304 RST MFLM MF50S A 130K PM1 A 3224 213811611503 RST MFLM MF50S A 15K PM1 A 3225 213811611304 RST MFLM MF50S A 130K PM1 A 3230 213811273103 CARBRST FLM CR25 10K PM5 3231 213811273103 CARBRST FLM CR25 10K PM5 3236 213811613002 RST MFLM MF5OS A 3K PM1 A 3237 213811614703 RST MFLM MF50S A 47K PM1 A 3238 213811614703 RST MFLM MF50S A 47K PM1 A 3239 213811614703 RST MFLM MF50S A 47K PM1 A 3241 213811273102 CARBRST FLM CR25 1K0 PM5 5 3242 213811273102 CARBRST FLM CR25 1K0 PM5 5 3243 213811273102 CARBRST FLM CR25 1K0 PM5 5 3244 213811273102 CARBRST FLM CR25 1K0 PM5 5 3246 213811273102 CARBRST FLM CR25 1K0 PM5 5 3247 213811273102 CARBRST FLM CR25 1K0 PM5 5 3248 213811273152 CARBRST FLM CR25 1K5 PM5 3249 213811611304 RST MFLM MF50S A 130K PM1 A 3250 213811611803 RST MFLM MF50S A 18K PM1 A 3251 213811611304 RST MFLM MF50S A 130K PM1 A 3252 213811611803 RST MFLM MF50S A 18K PM1 A 3253 213811611304 RST MFLM MF50S A 130K PM1 A 3254 213811611803 RST MFLM MF50S A 18K PM1 A 3255 213811611304 RST MFLM MF50S A 130K PM1 A 3256 213811611803 RST MFLM MF50S A 18K PM1 A 3257 213811611304 RST MFLM MF50S A 130K PM1 A 3258 213811611803 RST MFLM MF50S A 18K PM1 A 3259 213811611304 RST MFLM MF50S A 130K PM1 A 3260 213811611803 RST MFLM MF50S A 18K PM1 A 3261 213811611304 RST MFLM MF50S A 130K PM1 A 3262 213811611803 RST MFLM MF50S A 18K PM1 A 3263 213811611304 RST MFLM MF50S A 130K PM1 A 3264 213811611803 RST MFLM MF50S A 18K PM1 A 3269 213811611304 RST MFLM MF50S A 130K PM1 A 3270 213811615602 RST MFLM MF50S A 5K6 PM1 A 3271 213811611304 RST MFLM MF50S A 130K PM1 A 3272 213811615602 RST MFLM MF50S A 5K6 PM1 A 3273 213811611304 RST MFLM MF50S A 130K PM1 A 3274 213811615602 RST MFLM MF50S A 5K6 PM1 A 3275 213811611304 RST MFLM MF50S A 130K PM1 A 3276 213811615602 RST MFLM MF50S A 5K6 PM1 A 3277 213811612209 RST MFLM MF50S A 22R PM1 A 3278 213811612209 RST MFLM MF50S A 22R PM1 A 3280 213811612209 RST MFLM MF50S A 22R PM1 A � Go to cover page Forward Back 35 109P2 GS3 CM25 Spare Parts List Item Code Number Description 3283 213811612209 RST MFLM MF50S A 22R PM1 A 3284 213811612209 RST MFLM MF50S A 22R PM1 A 3286 213811612209 RST MFLM MF50S A 22R PM1 A 3287 213811612209 RST MFLM MF50S A 22R PM1 A 3292 213811616809 RST MFLM MF50S A 68R PM1 A 3293 213811616809 RST MFLM MF50S A 68R PM1 A 3295 213811616809 RST MFLM MF50S A 68R PM1 A 3296 213811616809 RST MFLM MF50S A 68R PM1 A 3301 213811203008 NETWORK RESISTOR 3302 213810113101 RST CRB CR12 A 100R PM5 A 3303 232273061103 RES 10K RC-11 SMD 0805 T 3304 213810113101 RST CRB CR12 A 100R PM5 A 3305 213810113104 RST CRB CR12 A 100K PM5 A 3307 232273061103 RES 10K RC-11 SMD 0805 T 3308 232273061103 RES 10K RC-11 SMD 0805 T 3309 213810113103 RST CRB CR12 A 10K PM5 A 3310 232273061472 RST SM 0805 RC11 4K7 PM5 R 3311 213810113104 RST CRB CR12 A 100K PM5 A 3312 213810113101 RST CRB CR12 A 100R PM5 A 3313 213810113101 RST CRB CR12 A 100R PM5 A 3314 213810113101 RST CRB CR12 A 100R PM5 A 3315 213810113101 RST CRB CR12 A 100R PM5 A 3316 232273061472 RST SM 0805 RC11 4K7 PM5 R 3317 213810113333 RST CRB CR12 A 33K PM5 A 3318 232273061103 RES 10K RC-11 SMD 0805 T 3319 213811611003 RST MFLM MF50S A 10K PM1 A 3320 213810113103 RST CRB CR12 A 10K PM5 A 3321 213810113101 RST CRB CR12 A 100R PM5 A 3322 213811618202 RST MFLM MF50S A 8K2 PM1 A 3323 232273061104 RES 100K RC-11 SMD 0805 T 3325 232273061472 RST SM 0805 RC11 4K7 PM5 R 3326 213810113472 RST CRB CR12 A 4K7 PM5 A 3327 213810113153 RST CRB CR12 A 15K PM5 A 3328 213811612701 RST MFLM MF50S A 270R PM1 A 3329 213811611509 RST MFLM MF50S A 15R PM1 A 3330 213810113153 RST CRB CR12 A 15K PM5 A 3331 213810113472 RST CRB CR12 A 4K7 PM5 A 3332 232273061103 RES 10K RC-11 SMD 0805 T 3333 232273061103 RES 10K RC-11 SMD 0805 T 3334 213810113101 RST CRB CR12 A 100R PM5 A 3335 213810113101 RST CRB CR12 A 100R PM5 A 3337 213810113222 RST CRB CR12 A 2K2 PM5 A 3338 213810113222 RST CRB CR12 A 2K2 PM5 A 3339 232273061103 RES 10K RC-11 SMD 0805 T 3340 232273061103 RES 10K RC-11 SMD 0805 T 3341 232273061103 RES 10K RC-11 SMD 0805 T 3342 232273061103 RES 10K RC-11 SMD 0805 T 3343 213810113103 RST CRB CR12 A 10K PM5 A 3354 213810113101 RST CRB CR12 A 100R PM5 A 3355 213810113101 RST CRB CR12 A 100R PM5 A 3393 232273061472 RST SM 0805 RC11 4K7 PM5 R 3394 232273061103 RES 10K RC-11 SMD 0805 T 3395 232273061472 RST SM 0805 RC11 4K7 PM5 R 3396 232273061103 RES 10K RC-11 SMD 0805 T 3397 213810113472 RST CRB CR12 A 4K7 PM5 A 3398 213810113101 RST CRB CR12 A 100R PM5 A 3401 232273061103 RES 10K RC-11 SMD 0805 T 3402 232273061222 RST SM 0805 RC11 2K2 PM5 R 3403 232273091002 RST SM 0805 JUMP. MAX 0R05 T 3404 213810113471 RST CRB CR12 A 470R PM5 A 3405 232273091002 RST SM 0805 JUMP. MAX 0R05 T 3421 213811612203 RST MFLM MF50S A 22K PM1 A 3422 213810113471 RST CRB CR12 A 470R PM5 A 3423 232273061472 RST SM 0805 RC11 4K7 PM5 R 3424 213810113101 RST CRB CR12 A 100R PM5 A 3425 232273061103 RES 10K RC-11 SMD 0805 T 3426 213810113101 RST CRB CR12 A 100R PM5 A 3427 213810113101 RST CRB CR12 A 100R PM5 A 3428 213810113225 RST CRB CR12 A 2M2 PM5 A 3429 232273061155 SMD R0805 1M5 PM5 3430 232273061101 RST SM 0805 RC11 100R PM5 R 3431 232273061332 RES 3K3 0805 SMD 3432 213811615101 RST MFLM MF50S A 510R PM1 A 3433 213811612802 RST MFLM MF50S A 2K8 PM1 A 3434 232273061472 RST SM 0805 RC11 4K7 PM5 R Item Code Number Description 3441 213811613903 RST MFLM MF50S A 39K PM1 A 3442 213811612204 RST MFLM MF50S A 220K PM1 3443 213810113683 RST CRB CR12 A 68K PM5 A 3444 232273091002 RST SM 0805 JUMP. MAX 0R05 T 3445 232273061564 SMD R0805 560K PM5 3446 232273061123 RES 12K RC-11 SMD 0805 T 3450 230620403828 RST MFLM NFR25 1/4W 8R2 PM5 3451 232273061122 RST SMC 0805 RC11 1K2 PM5 T 3456 230620403828 RST MFLM NFR25 1/4W 8R2 PM5 3457 232273061122 RST SMC 0805 RC11 1K2 PM5 T 3458 213811273471 CARBRST FLM CR25 470R PM5 3462 213810113103 RST CRB CR12 A 10K PM5 A 3464 232273061153 RST SM 0805 RC11 15K PM5 R 3465 213810113103 RST CRB CR12 A 10K PM5 A 3466 213810113103 RST CRB CR12 A 10K PM5 A 3467 232273061472 RST SM 0805 RC11 4K7 PM5 R 3468 213810113472 RST CRB CR12 A 4K7 PM5 A 3469 213811273473 CARBRST FLM CR25 47K PM5 3470 213810113221 RST CRB CR12 A 220R PM5 A 3471 213810113473 RST CRB CR12 A 47K PM5 A 3472 213811617503 RST MFLM MF50S A 75K PM1 A 3473 213811611003 RST MFLM MF50S A 10K PM1 A 3474 213811611504 RST MFLM MF50S A 150K PM1 A 3475 213811273103 CARBRST FLM CR25 10K PM5 3476 213811611005 RST MFLM MF50S A 1M PM1 A 3491 232273061473 RST SM 0805 RC11 47K PM5 R 3492 232273061473 RST SM 0805 RC11 47K PM5 R 3493 213810113101 RST CRB CR12 A 100R PM5 A 3494 232273061101 RST SM 0805 RC11 100R PM5 R 3495 213810113101 RST CRB CR12 A 100R PM5 A 3501 213810500335 5W 680R RSM 6E 3502 213810500334 5W 2K2 RSM 6E 3503 213810113479 RST CRB CR12 A 47R PM5 A 3504 213810113103 RST CRB CR12 A 10K PM5 A 3505 213810500335 5W 680R RSM 6E 3506 213810500408 RST MOX 7W RSH S 1R8 3507 213811616809 RST MFLM MF50S A 68R PM1 A 3515 213810500074 TST MOX5W RSM5WL S 150R PM5 B 3516 213810500076 RST MOX 5W 330R RSS PM5 3517 213811614701 RST MFLM MF50S A 470R PM1 A 3518 213811614701 RST MFLM MF50S A 470R PM1 A 3519 213811616809 RST MFLM MF50S A 68R PM1 A 3520 213811273102 CARBRST FLM CR25 1K0 PM5 5 3521 213811616809 RST MFLM MF50S A 68R PM1 A 3522 213811604478 RST MFLM MF50S A 4R7 PM5 A 3523 230620403159 MET FLM RST NFR25 15R PM5 3524 230620403159 MET FLM RST NFR25 15R PM5 3525 213811273471 CARBRST FLM CR25 470R PM5 3527 232273061103 RES 10K RC-11 SMD 0805 T 3528 213810113101 RST CRB CR12 A 100R PM5 A 3529 232273061103 RES 10K RC-11 SMD 0805 T 3530 232273061182 RES 1K8 0805 SMD 3531 213811273122 CARBRST FLM CR25 1K2 PM5 3541 213810113121 RST CRB CR12 A 120R PM5 A 3542 213810113103 RST CRB CR12 A 10K PM5 A 3544 213811611009 RST MFLM MF50S A 10R PM1 A 3545 213810500095 RST MOX 7W RSH S 33R PM5 3546 232220733479 RST MFLM NFR25H 47R PM5 3551 230620403108 RST FUSE NFR25 S 1R0 PM5 A 3552 230620403108 RST FUSE NFR25 S 1R0 PM5 A 3553 213811612202 RST MFLM MF50S A 2K2 PM1 A 3554 213811611203 RST MFLM MF50S A 12K PM1 A 3555 232273061103 RES 10K RC-11 SMD 0805 T 3556 232273061202 RES 2K RC-11 SMD 0805 T 3566 213810113472 RST CRB CR12 A 4K7 PM5 A 3569 232220733108 MET FLM RST NFR25H 1R0 PM5 T 3570 213811612202 RST MFLM MF50S A 2K2 PM1 A 3571 213811273471 CARBRST FLM CR25 470R PM5 3572 213811273471 CARBRST FLM CR25 470R PM5 3576 213811612202 RST MFLM MF50S A 2K2 PM1 A 3577 232220733108 MET FLM RST NFR25H 1R0 PM5 T 3578 213811614709 RST MFLM MF50S A 47R PM1 A 3579 213811273188 RES CR25 1/4W 1R8 3580 213811604228 RST MFLM MF50S A 2R2 PM5 A 3581 213811614701 RST MFLM MF50S A 470R PM1 A � Go to cover page Forward Back 36 109P2 GS3 CM25 Spare Parts List Item CodeNumber Description 3582 213811273188 RES CR25 1/4W 1R8 3586 213810113102 RST CRB CR12 A 1K PM5 A 3587 213811617502 RST MFLM MF50S A 7K5 PM1 A 3588 213811273152 CARBRST FLM CR25 1K5 PM5 3589 213810113222 RST CRB CR12 A 2K2 PM5 A 3590 232220533479 MET FLM RST NFR25 47R PM5PM5 T 3591 232220533479 MET FLM RST NFR25 47R PM5PM5 T 3592 213811614701 RST MFLM MF50S A 470R PM1 A 3593 213811615609 RST MFLM MF50S A 56R PM1 A 3601 232224213224 METGLAZ RST A VR37 220K PM5 T 3602 212010592168 MET FLM RST 2W 10K PM5 6E B 3603 823827437071 MEF FLM RST 2W 3K9 PM5 RSS B 3604 213811613303 RST MFLM MF50S A 33K PM1 A 3605 232224213104 METGLAZ RST A VR37 100K 3606 232224213105 METGLAZ RST A VR37 1M PM5 T 3607 232224213105 METGLAZ RST A VR37 1M PM5 T 3608 213811273332 CARBRST FLM CR25 3K3 PM5 3609 212010128152 CARBRST COMP 1/2W 1K5 PM10 3610 232273091002 RST SM 0805 JUMP. MAX 0R05 T 3611 213810113393 RST CRB CR12 A 39K PM5 A 3612 232273061223 RES 22K 0805 SMD 3613 213811614701 RST MFLM MF50S A 470R PM1 A 3614 232273061104 RES 100K RC-11 SMD 0805 T 3615 213811273392 CARBRST FLM CR25 3K9 PM5 3616 232224213105 METGLAZ RST A VR37 1M PM5 T 3617 212010128222 RST CMP ERC12 A 2K2 PM10 A 3618 232273091002 RST SM 0805 JUMP. MAX 0R05 T 3622 232273061104 RES 100K RC-11 SMD 0805 T 3623 213810113103 RST CRB CR12 A 10K PM5 A 3624 232273061104 RES 100K RC-11 SMD 0805 T 3625 213810113103 RST CRB CR12 A 10K PM5 A 3626 232273061104 RES 100K RC-11 SMD 0805 T 3627 213810113103 RST CRB CR12 A 10K PM5 A 3628 232273061104 RES 100K RC-11 SMD 0805 T 3629 213810113103 RST CRB CR12 A 10K PM5 A 3630 232273061104 RES 100K RC-11 SMD 0805 T 3631 213810113103 RST CRB CR12 A 10K PM5 A 3632 232273061104 RES 100K RC-11 SMD 0805 T 3633 213810113103 RST CRB CR12 A 10K PM5 A 3634 213811273222 CARBRST FLM CR25 2K2 PM5 T 3652 232273061472 RST SM 0805 RC11 4K7 PM5 R 3653 213811273129 CARBRST FLM R25 12R PM5 3654 232273061154 RST SM 0805 RC11 150K PM5 R 3656 232273061472 RST SM 0805 RC11 4K7 PM5 R 3657 232273061472 RST SM 0805 RC11 4K7 PM5 R 3658 213810113332 RST CRB CR12 A 3K3 PM5 A 3659 213811615602 RST MFLM MF50S A 5K6 PM1 A 3660 232273061562 RES 5.6K RC-11 SMD 0805 T 3661 232273061479 RES 47R 0805 SMD RC-11 T 3662 232273061472 RST SM 0805 RC11 4K7 PM5 R 3663 232273464702 SMD RST 0805 4K7 PM1 3664 232273061332 RES 3K3 0805 SMD 3665 232273061103 RES 10K RC-11 SMD 0805 T 3666 232273061105 RES 1M RC-11 SMD 0805 T 3667 232273061472 RST SM 0805 RC11 4K7 PM5 R 3668 232273061223 RES 22K 0805 SMD 3671 213811611005 RST MFLM MF50S A 1M PM1 A 3672 232220533478 RST FUSE NFR25 S 4R7 PM5 3673 232273061824 RES 820K 0805 SMD 3674 213811611002 RST MFLM MF50S A 1K PM1 A 3675 213811611009 RST MFLM MF50S A 10R PM1 A 3676 213811611003 RST MFLM MF50S A 10K PM1 A 3677 212010592444 RES 2W 68R 3678 213811273101 CARBRST FLM CR25 100R PM5 3679 213811273471 CARBRST FLM CR25 470R PM5 3680 213811273103 CARBRST FLM CR25 10K PM5 3681 213811611009 RST MFLM MF50S A 10R PM1 A 3682 232224213104 METGLAZ RST A VR37 100K 3683 212010128102 CARBRST COMP 1/2W 1K0 PM10 3684 213811614702 RST MFLM MF50S A 4K7 PM1 A 3685 213811273103 CARBRST FLM CR25 10K PM5 3686 232273061272 RES 2K7 0805 SMD 3687 232273061103 RES 10K RC-11 SMD 0805 T 3688 232273061393 RES 39K RC-11 SMD 0805 T 3689 213810113153 RST CRB CR12 A 15K PM5 A Item Code Number Description 3690 213810113102 RST CRB CR12 A 1K PM5 A 3691 212010128152 CARBRST COMP 1/2W 1K5 PM10 3692 232224213684 METGLAZ RST A VR37 680K PM5 3693 213811611004 RST MFLM MF50S A 100K PM1 A 3694 213811618203 RST MFLM MF50S A 82K PM1 A 3695 213836500102 RTRM CER LIN 20K H VG067TL1 B 3696 213811611005 RST MFLM MF50S A 1M PM1 A 3697 213811618203 RST MFLM MF50S A 82K PM1 A 3698 213836500102 RTRM CER LIN 20K H VG067TL1 B 3700 232273061102 RST SMC 0805 RC11 1K PM5 T 3701 232273467509 RST SM 0805 RC11 75R PM1 T 3702 232273061479 RES 47R 0805 SMD RC-11 T 3703 232273061229 RST SM 0805 RC11 22R PM5 R 3704 232273061569 RST SMD 0805 RC11 56R PM5 3705 232273061105 RES 1M RC-11 SMD 0805 T 3706 213811615603 RST MFLM MF50S A 56K PM1 A 3707 213810113224 RST CRB CR12 A 220K PM5 A 3708 232273061823 SMD R0805 82K PM5 3709 212010128479 CARBRST COMP 1/2W 47R PM10 3710 232273061102 RST SMC 0805 RC11 1K PM5 T 3711 232273061123 RES 12K RC-11 SMD 0805 T 3712 232273061102 RST SMC 0805 RC11 1K PM5 T 3713 232273061101 RST SM 0805 RC11 100R PM5 R 3714 232273061101 RST SM 0805 RC11 100R PM5 R 3715 232273061101 RST SM 0805 RC11 100R PM5 R 3717 232273061471 RST SM 0805 RC11 470R PM5 R 3718 232273061471 RST SM 0805 RC11 470R PM5 R 3721 232273467509 RST SM 0805 RC11 75R PM1 T 3722 232273061479 RES 47R 0805 SMD RC-11 T 3723 232273061229 RST SM 0805 RC11 22R PM5 R 3724 232273061479 RES 47R 0805 SMD RC-11 T 3725 232273061105 RES 1M RC-11 SMD 0805 T 3726 213811615603 RST MFLM MF50S A 56K PM1 A 3727 213810113224 RST CRB CR12 A 220K PM5 A 3728 232273061823 SMD R0805 82K PM5 3729 212010128479 CARBRST COMP 1/2W 47R PM10 3730 232273061102 RST SMC 0805 RC11 1K PM5 T 3731 232273061123 RES 12K RC-11 SMD 0805 T 3732 232273061222 RST SM 0805 RC11 2K2 PM5 R 3733 232273061181 RES 180R 0805 SMD 3734 232273061101 RST SM 0805 RC11 100R PM5 R 3735 232273061471 RST SM 0805 RC11 470R PM5 R 3736 232273061101 RST SM 0805 RC11 100R PM5 R 3737 232273061105 RES 1M RC-11 SMD 0805 T 3738 232273061105 RES 1M RC-11 SMD 0805 T 3741 232273467509 RST SM 0805 RC11 75R PM1 T 3742 232273061479 RES 47R 0805 SMD RC-11 T 3743 232273061229 RST SM 0805 RC11 22R PM5 R 3744 232273061569 RST SMD 0805 RC11 56R PM5 3745 232273061105 RES 1M RC-11 SMD 0805 T 3746 213811615603 RST MFLM MF50S A 56K PM1 A 3747 213810113224 RST CRB CR12 A 220K PM5 A 3748 232273061823 SMD R0805 82K PM5 3749 212010128479 CARBRST COMP 1/2W 47R PM10 3750 232273061102 RST SMC 0805 RC11 1K PM5 T 3751 232273061123 RES 12K RC-11 SMD 0805 T 3760 212010128153 CARBRST COMP 1/2W 15K PM10 3761 213811273471 CARBRST FLM CR25 470R PM5 3763 212010128152 CARBRST COMP 1/2W 1K5 PM10 3765 213811611804 RST MFLM MF50S A 180K PM1 A 3766 232273061101 RST SM 0805 RC11 100R PM5 R 3767 232273061101 RST SM 0805 RC11 100R PM5 R 3768 232273061102 RST SMC 0805 RC11 1K PM5 T 3769 232273061152 RST SM 0805 RC11 1K5 PM5 R 3781 232273061562 RES 5.6K RC-11 SMD 0805 T 3782 232273061152 RST SM 0805 RC11 1K5 PM5 R 3783 232273061182 RES 1K8 0805 SMD 3784 232273061105 RES 1M RC-11 SMD 0805 T 3785 232273061102 RST SMC 0805 RC11 1K PM5 T 3786 232273061103 RES 10K RC-11 SMD 0805 T 3787 232273061332 RES 3K3 0805 SMD 3788 232273061101 RST SM 0805 RC11 100R PM5 R 3789 232273061101 RST SM 0805 RC11 100R PM5 R 3790 232273061103 RES 10K RC-11 SMD 0805 T 3791 232273061332 RES 3K3 0805 SMD � Go to cover page Forward Back 37 109P2 GS3 CM25 Spare Parts List Item Code Number Description 3792 232273464702 SMD RST 0805 4K7 PM1 3801 232273061472 RST SM 0805 RC11 4K7 PM5 R 3802 232273061562 RES 5.6K RC-11 SMD 0805 T 3803 232273061472 RST SM 0805 RC11 4K7 PM5 R 3804 232273061105 RES 1M RC-11 SMD 0805 T 3805 232273061103 RES 10K RC-11 SMD 0805 T 3806 232273061331 RST SM 0805 RC11 330R PM5 T 3807 232273061153 RST SM 0805 RC11 15K PM5 R 3808 232273061123 RES 12K RC-11 SMD 0805 T 3809 232273061224 RST SMD 0805 RC11 220K PM5 R 3811 232273061184 RST SMD 0805 RC11 180K PM5 T 3812 232273061684 RES 680K 0805 SMD 3813 232273061473 RST SM 0805 RC11 47K PM5 R 3815 232273061103 RES 10K RC-11 SMD 0805 T 3816 232273061102 RST SMC 0805 RC11 1K PM5 T 3821 232273061184 RST SMD 0805 RC11 180K PM5 T 3822 232273061684 RES 680K 0805 SMD 3823 232273061473 RST SM 0805 RC11 47K PM5 R 3825 232273061103 RES 10K RC-11 SMD 0805 T 3831 232273061184 RST SMD 0805 RC11 180K PM5 T 3832 232273061684 RES 680K 0805 SMD 3833 232273061473 RST SM 0805 RC11 47K PM5 R 3835 232273061103 RES 10K RC-11 SMD 0805 T 3836 232273061103 RES 10K RC-11 SMD 0805 T 3841 232273061103 RES 10K RC-11 SMD 0805 T 3842 232273061103 RES 10K RC-11 SMD 0805 T 3843 232273061103 RES 10K RC-11 SMD 0805 T 3844 232273061103 RES 10K RC-11 SMD 0805 T 3845 232273061101 RST SM 0805 RC11 100R PM5 R 3846 232273061101 RST SM 0805 RC11 100R PM5 R 3891 213811611004 RST MFLM MF50S A 100K PM1 A 3892 213811615603 RST MFLM MF50S A 56K PM1 A 3893 213811611503 RST MFLM MF50S A 15K PM1 A 3894 213811612003 RST MFLM MF50S A 20K PM1 A 3895 213811612403 RST MFLM MF50S A 24K PM1 A 5001 242253597069 COIL 4U7 K 0305 5002 242253597069 COIL 4U7 K 0305 5003 242253597069 COIL 4U7 K 0305 5101 313816873611 LINE FILTER (HJC-K8259) 5102 313816874511 FERRITE BEAD+COIL C8BR6H6X9.2A 5103 313816874511 FERRITE BEAD+COIL C8BR6H6X9.2A 5104 242254940662 FERRITE BEAD 0.7UH 5130 313816874281 POWER TRANSFORMER-EE42 5301 242253597069 COIL 4U7 K 0305 5302 242253597069 COIL 4U7 K 0305 5501 313811879961 H/DRV. XFMR 5502 313816874061 BEAD BF30UTA-3.5X5X1B 5503 313816873551 LINEARITY COIL(54A-9050H) 5504 313816873541 LINEARITY COIL(54A-9049H) 5505 313816874061 BEAD BF30UTA-3.5X5X1B 5542 242253591023 CHOCK COIL 22UH 5543 313812874431 HOR.CENTERING TRAN. 5544 313811878951 H SHIFT CHOKE COIL 5545 313812874421 PUNK HEAD CHOKE 5601 313812874411 DAF TRANSFORMER 5670 242253597069 COIL 4U7 K 0305 5671 313816876541 L.O.T. 5672 242253591023 CHOCK COIL 22UH 5701 242253597069 COIL 4U7 K 0305 5702 313817876911 COIL 0.12UH PM10 5703 242254944197 BLM21P221SB-0805 SMD 5721 313817876911 COIL 0.12UH PM10 5722 242254944197 BLM21P221SB-0805 SMD 5731 313817876911 COIL 0.12UH PM10 5732 242254944197 BLM21P221SB-0805 SMD 5733 242254944197 BLM21P221SB-0805 SMD 5734 242253597069 COIL 4U7 K 0305 5735 242254944197 BLM21P221SB-0805 SMD 5736 242254944197 BLM21P221SB-0805 SMD 5737 242254944197 BLM21P221SB-0805 SMD 5760 313816874511 FERRITE BEAD+COIL C8BR6H6X9.2A 5761 242254944197 BLM21P221SB-0805 SMD Item Code Number Description 5762 242254944197 BLM21P221SB-0805 SMD 5763 242254944197 BLM21P221SB-0805 SMD 5764 242254944197 BLM21P221SB-0805 SMD 5765 242254944197 BLM21P221SB-0805 SMD 5766 242253597069 COIL 4U7 K 0305 5767 313816874511 FERRITE BEAD+COIL C8BR6H6X9.2A 5768 242254942026 IND FXD BEAD EMI 100MHZ 50E A 5781 242253597069 COIL 4U7 K 0305 5782 242253597069 COIL 4U7 K 0305 5783 313817878601 BEAD 0.7UH VERT. 5791 242253597069 COIL 4U7 K 0305 5801 242254944197 BLM21P221SB-0805 SMD 5891 242254944197 BLM21P221SB-0805 SMD 6101 931900263671 BRIDGE GBU6J 6104 933703700133 DIO REC BYV26E A A 6109 319801027581 DIODE BZX79C 7V5 6111 319801021591 DIODE BZX79-C15 (UAW) 6112 933703700133 DIO REC BYV26E A A 6113 319801010071 DIODE BAV21 (UAW) 6114 319801010531 SMD DIODE BAV103 6115 319801010071 DIODE BAV21 (UAW) 6116 933751660683 DIODE RGP10D (GI) 6125 319801010011 DIODE 1N4148 (UAW) 6131 932212636682 DIODE 31DF6 6E 6132 319801021591 DIODE BZX79-C15 (UAW) 6133 932212636682 DIODE 31DF6 6E 6134 932208187683 DIODE BYW98-200 6135 932208187683 DIODE BYW98-200 6137 932208187683 DIODE BYW98-200 6139 932208187683 DIODE BYW98-200 6140 933890390682 DIO REC EGP20D 6144 933703700133 DIO REC BYV26E A A 6145 319801010071 DIODE BAV21 (UAW) 6152 319801026881 DIODE BZX79-C6V8 (UAW) 6160 933913910115 SMD DIODE BAS32L 6161 319801010071 DIODE BAV21 (UAW) 6162 319801010531 SMD DIODE BAV103 6191 933497950683 DIODE RGP10J (GI) 6192 319801010071 DIODE BAV21 (UAW) 6201 933166890113 DIODE BZX79-B12V 6202 932214729673 DIODE BZX55-B2V4 (UAW) 6203 319801010011 DIODE 1N4148 (UAW) 6204 319801010011 DIODE 1N4148 (UAW) 6205 319801010011 DIODE 1N4148 (UAW) 6206 319801010011 DIODE 1N4148 (UAW) 6207 319801025681 DIODE BZX79-C5V6 (UAW) 6208 319801025681 DIODE BZX79-C5V6 (UAW) 6301 933913910115 SMD DIODE BAS32L 6302 319801010011 DIODE 1N4148 (UAW) 6391 933215370215 SMD DIODE BAV99 6392 933215370215 SMD DIODE BAV99 6421 319801010011 DIODE 1N4148 (UAW) 6422 933957760683 DIODE SB140 (GI) 6423 933913910115 SMD DIODE BAS32L 6424 319801010011 DIODE 1N4148 (UAW) 6426 319801010011 DIODE 1N4148 (UAW) 6462 319801023091 DIODE BZX79C30V 6463 933913910115 SMD DIODE BAS32L 6464 319801025181 DIODE BZX79-C5V1 (UAW) 6491 319801010011 DIODE 1N4148 (UAW) 6492 319801010011 DIODE 1N4148 (UAW) 6501 933493960683 DIODE RGP10G (GI) 6502 933751660683 DIODE RGP10D (GI) 6503 319801010011 DIODE 1N4148 (UAW) 6506 933543490133 DIO REC BYV27-50 6507 933712740673 DIODE BZX79-B15 6508 932213602687 DIODE 5TUZ52C 6515 933703700133 DIO REC BYV26E A A 6540 933497950683 DIODE RGP10J (GI) 6541 319801010011 DIODE 1N4148 (UAW) 6542 319801010011 DIODE 1N4148 (UAW) 6543 932211574682 DIODE 31DF4 � Go to cover page Forward Back 38 109P2 GS3 CM25 Spare Parts List Item Code Number Description 6544 933751660683 DIODE RGP10D (GI) 6545 933751660683 DIODE RGP10D (GI) 6566 319801010011 DIODE 1N4148 (UAW) 6567 933504400683 DIODE RGP15G (GI) 6601 933612320113 DIODE BY584 6602 319801021291 DIODE BZX79-C12 (UAW) 6603 933612320113 DIODE BY584 6621 319801010011 DIODE 1N4148 (UAW) 6622 319801025181 DIODE BZX79-C5V1 (UAW) 6651 933751660683 DIODE RGP10D (GI) 6652 319801025181 DIODE BZX79-C5V1 (UAW) 6653 933913910115 SMD DIODE BAS32L 6654 933913910115 SMD DIODE BAS32L 6655 319801025181 DIODE BZX79-C5V1 (UAW) 6671 933497950683 DIODE RGP10J (GI) 6672 932210388682 DIO REC 31DF6 A (INRO) B 6673 319801010011 DIODE 1N4148 (UAW) 6674 933612320113 DIODE BY584 6691 319801027591 DIODE BZX79-C75(UAW) 6701 319801010531 SMD DIODE BAV103 6702 319801010531 SMD DIODE BAV103 6703 319801010531 SMD DIODE BAV103 6704 319801010531 SMD DIODE BAV103 6705 933913910115 SMD DIODE BAS32L 6721 319801010531 SMD DIODE BAV103 6722 319801010531 SMD DIODE BAV103 6723 319801010531 SMD DIODE BAV103 6724 319801010531 SMD DIODE BAV103 6725 933913910115 SMD DIODE BAS32L 6731 933913910115 SMD DIODE BAS32L 6732 933215370215 SMD DIODE BAV99 6741 319801010531 SMD DIODE BAV103 6742 319801010531 SMD DIODE BAV103 6743 319801010531 SMD DIODE BAV103 6744 319801010531 SMD DIODE BAV103 6745 933913910115 SMD DIODE BAS32L 6761 933493960683 DIODE RGP10G (GI) 6762 319801023091 DIODE BZX79C30V 6801 933913910115 SMD DIODE BAS32L 6802 933913910115 SMD DIODE BAS32L 6803 933913910115 SMD DIODE BAS32L 6811 933137380215 Z.DIODE BZX84C4V7 SMD T 6812 933913910115 SMD DIODE BAS32L 6813 933215370215 SMD DIODE BAV99 6821 933137380215 Z.DIODE BZX84C4V7 SMD T 6822 933913910115 SMD DIODE BAS32L 6823 933215370215 SMD DIODE BAV99 6831 933137380215 Z.DIODE BZX84C4V7 SMD T 6832 933913910115 SMD DIODE BAS32L 6833 933215370215 SMD DIODE BAV99 6891 932214603682 LED L-3WYGW 7001 932214260682 IC AN5870K 30P 7111 319802043011 TRANS BF422 (UAW) 7121 932214576682 IC STRF6656 (LF1352) 7130 932214014667 PHOTOCOUPLER TCET1103G 4P 7140 933535800682 TRANS. BD438 B 7141 932209265685 TRAN MUN2211 7143 932209200687 IC L4940V5 3P 7144 933773970687 MOSFET IRF640 7146 934003960126 TRANS BSN254A 7147 932209265685 TRAN MUN2211 7148 319801042081 TRANS BC848C (UAW) 7151 319802043541 TRANS BC337-40 (UAW) R 7155 933771100686 IC TL431CLPRP 3P 7161 319802043561 TRANS BC338 (UAW) 7162 932209265685 TRAN MUN2211 7163 319801042081 TRANS BC848C (UAW) 7191 319802040161 TRANS BC558C (UAW) 7201 932213999682 IC LM61BIZ 3P 7203 933393510602 IC LM358N 8P (PHILIPS) 7204 933768130112 IC PCF8591P 16P 7205 935229830112 IC TDA8447/N1 16P Item Code Number Description 7391 932209265685 TRAN MUN2211 7392 319801042201 TRANS BC858C (UAW) 7401 319802043461 TRANS BC328 (UAW) 7402 932209265685 TRAN MUN2211 7404 933282660652 IC HEF4053BP 16P 7421 935262332112 IC TDA4856/V2 32P 7422 319802043561 TRANS BC338 (UAW) 7423 319802043461 TRANS BC328 (UAW) 7424 932209265685 TRAN MUN2211 7425 319802040081 TRANS BC548C (UAW) 7426 319802040161 TRANS BC558C (UAW) 7427 319801042201 TRANS BC858C (UAW) 7461 933237780126 TRANS BC546B (UAW) 7462 319802040081 TRANS BC548C (UAW) 7463 319802040161 TRANS BC558C (UAW) 7464 319802043021 TRANS BF423 (UAW) 7465 319802043011 TRANS BF422 (UAW) 7466 932209265685 TRAN MUN2211 7491 932209898682 IC ST24LC21BB6 8P 7501 934000540115 TRANS BSP126 7502 932214442671 TRANS 2SC5445 7503 932205702687 TRANS BD533 7504 932205703687 TRANS BD534 7505 933393510602 IC LM358N 8P (PHILIPS) 7541 932211829687 FET POW 2SJ448 7542 932204822682 TRANS 2SC2344E (SANYO) 7543 932204823682 TRANS 2SA1011E 7544 319801042201 TRANS BC858C (UAW) 7545 319802043011 TRANS BF422 (UAW) 7566 932209265685 TRAN MUN2211 7567 931900234682 IC STV9379 7P 7586 933393510602 IC LM358N 8P (PHILIPS) 7587 319802043841 TRANS BC639 (UAW) 7588 319802043811 TRANS BC638 (UAW) 7601 933271570127 TRANSISTOR BUX87 7602 319801042081 TRANS BC848C (UAW) 7603 319801042081 TRANS BC848C (UAW) 7621 933773970687 MOSFET IRF640 7622 932214562667 TRAN SLA5058 7628 932209265685 TRAN MUN2211 7629 932209265685 TRAN MUN2211 7630 932209265685 TRAN MUN2211 7631 932209265685 TRAN MUN2211 7632 932209265685 TRAN MUN2211 7633 932209265685 TRAN MUN2211 7651 932212152682 IC L4990A 16P 7652 319802040081 TRANS BC548C (UAW) 7653 319801042201 TRANS BC858C (UAW) 7654 319801042081 TRANS BC848C (UAW) 7671 934003960126 TRANS BSN254A 7672 931900179687 IRF740 POWER MOS-FET 7673 932212460687 FET POW STU8NA80 (ST00) L 7674 319802040081 TRANS BC548C (UAW) 7701 935261628112 IC TDA4886A/V1 24P 7705 932213801667 IC LM2402T 11P 7706 319802043011 TRANS BF422 (UAW) 7707 319802043011 TRANS BF422 (UAW) 7726 319802043011 TRANS BF422 (UAW) 7727 319802043011 TRANS BF422 (UAW) 7746 319802043011 TRANS BF422 (UAW) 7747 319802043011 TRANS BF422 (UAW) 7781 823827435561 IC LSC4588P2 7782 932209265685 TRAN MUN2211 7783 932209265685 TRAN MUN2211 7801 932203171682 IC TL072CP 8P (TI) 7802 933669110652 IC 74HC4066N 14P 7803 319802043021 TRANS BF423 (UAW) 7301 313817854161 109P2-OTP CPU ASSY 7302 319801042201 TRANS BC858C (UAW) 7303 319801042081 TRANS BC848C (UAW) 7336 932212662682 IC M24C16-BN6 8P 7363 933400610682 IC MC7812CT 3P 7364 933920810682 IC L7808CV 3P � Go to cover page Forward Back 39 109P2 GS3 CM25 Spare Parts List Item Code Number Description 7804 319802043021 TRANS BF423 (UAW) 7805 319802043021 TRANS BF423 (UAW) 7806 933706060112 IC PCF8574P 16P 7807 319801042081 TRANS BC848C (UAW) 7808 319802043021 TRANS BF423 (UAW) 7809 319802043021 TRANS BF423 (UAW) 7810 319802043021 TRANS BF423 (UAW) 7891 823827434991 LM61BIM (SOT-23) � Go to cover page Forward Back Repair Flow Chart 40 109P2 GS3 CM25 A. Power Supply Failure 1. Sympton : no startup sound LED light off check 7121 pin1 Waveform right? check 7121 pin2 Ok NO check 7121 pin 3 check 1103/6101/ 7121 pin3/2103 Ok NO check 3121/3123 replace 7121 NO check 7121 pin4 check 6125 2. Sympton : hicup mode with startup sound or blinking LED check 3121,3123,3125 check 7121 pin 4 check 6161 Ok replace 7121 check 6111/3106/ 3111/7111 Ok NO OK No replace 5130 No check 7143 pin3 voltage dip check 7143 pin1 12V< pin1 < 15V check 7121 pin 1 Ok check 6152/3151/3153 7151/2142 No check +5V loading current Turn power off check the resistance for all output voltages+210, 80,+15,-15,+6.3,+5V,check 6131,6133,6134,6137,6139 replace 5130 check 7141/7155/7144/7151 3. Sympton: abnormal sound check 7121 drain waveform right? check frequency Ok Ok No check 6104/3104/3105 2103/2104/2121 replace 5130 No OK Ok � Go to cover page Forward Back B.Video Repair Flow check 7701 pin11 HFLB 1.Sympton : (with white pattern) no picture green LED on check EHT~25KV rough check for R, G, B 1. video input= 0.7V 2. 7701video output =2.5V 3. 7705 video output= 35V swing check 7701 pin5 CLBL check DC restoration 7707,7727,7747 7706,7726,7746 check 7701 pin24 2V< ABL < 5V check 7701 pin 6,8,10 input swing check 7705 pin8,9,11 input swing Ok replace 7705 replace IF cable No No replace 7701 check VG1 < -190V Ok No check blanking 7421 pin16 check heater = 6.3V Ok check Xray prot. 7651 pin14 No 2.Sympton : no video (or dim), only raster with/without retrace line green LED on check Vg1 Vg1 = 0V check cathode +80V/+180V Ok check blanking 7421 pin16 No turn down Vg2 check 7705 pin 1,3, 5 output swing check 7421 pin16 check VG2 > 350V Ok No check 7781 pin10 VFLB 3. Sympton : no OSD or OSD out of sync. check 7701 pin 2,3,4 input check 7701 pin1 check 7781 pin2 VCO pin3 RP check 7781 pin5 HFLB replace 7701 Ok No replace 7781 No check 7781 pin 7,8(IIC) Ok No check 7781 pin12 Ok Repair Flow Chart 41 109P2 GS3 CM25 � Go to cover page Forward Back C. Horizontal deflection output repair flow : 1. Sympton : without H-deflection. 2. Sympton : East /West corr. 7421 pin6 check 210V check Hsync 7541 drain refer 7421 check list or replace 7421 No Ok check 6604,5542,3546 Ok No replace 5543 4. Sympton : rotation check 7505 pin 2,3,8 enter factory mode check linearity data in eeprom check 7586 pin 1,4,8 check 3528/7503 7504 emitter check 7421 pin11 parabola exist check 2443 parabola exist 3. Sympton : H-linearity /H-DC (full freq. range) replace 3523 check 7502 refer 7421 check list 5. Sympton : H_dc shift check 7542,7543 check 7421 pin 32 enter OSD function disable morier check 7601collector check 7545 collector 7544 emitter 6. Sympton : Focus check B+ Control 7422,7423 base check B+ Control 7541 base check B+ Control check B+ Control 7421 base refer cpu chece list check cpu pin 19~25 check cpu 7301 pin4 control range check 3590/7587 /7588 check cpu 7301 pin28 control range check 3617/5672/5601 Repair Flow Chart 42 109P2 GS3 CM25 � Go to cover page Forward Back D. Vertical Deflection Failure check 3578,3580 good basic check +15/-15V Sympton : one horizontal line V_size is abnormal too large/small (small) check 7567 pin2,pin3 ramp exist ? check +15V,3569,6567 good? replace 3578,3580,7567 No Ok replace 3569,6567,7567 Ok No check 7421 check 3571,3572 Ok No Repair Flow Chart 43 109P2 GS3 CM25 � Go to cover page Forward Back Repair Flow Chart 44 109P2 GS3 CM25 E. CPU check list check cpu pin11/pin32=5V pin9/pin10=12MhZ pin12/pin31=gnd pin7 pin6 normal hi hi standby hi low off low low suspend low hi 13,14,16,17 Hsync/Vsync 18. Hunlock check sync. hin=pin13 vin=pin16 hout=pin14 vout=pin17 check pin42 pwm from 0V to 5V Basic Check 2. H-Centering check Q1~Q6 Pin20~25 low : 0 hi :1 7. ABL-Adj 1. H-linearity Pin20~25 (S6~S1) S-cap switch check pin29 pwm from 0V to 5V check pin28 pwm from 0V to 5V 1. Normal Fvout=Fvin 2. sync out of rang Fhin>110KHz Fvin>160Hz check pin18 normal=Hi blank=low 6.7 P.S. LED check pin6/7 3. Blank check pin2 normal : low change timing : Hi Hor. Freq.(KHz) Q6 Q5 Q4 Q3 Q2 Q1 ~33.00 1 1 1 1 1 1 33.00~36.00 0 0 0 0 1 1 36.00~42.00 0 0 0 1 0 1 42.00~45.00 0 0 1 1 1 0 45.00~47.50 0 1 1 0 1 0 47.50~49.00 1 0 1 0 1 0 49.00~52.00 1 0 0 0 1 0 52.00~55.00 0 0 0 0 1 0 55.00~58.50 1 1 1 1 0 0 58.50~61.50 0 1 1 1 0 0 61.50~65.00 1 1 0 1 0 0 65.00~70.00 0 0 0 1 0 0 70.00~73.00 0 0 0 1 0 0 73.00~76.00 0 1 1 0 0 0 76.00~82.50 1 0 1 0 0 0 82.50~88.50 0 0 1 0 0 0 88.50~98.00 1 1 0 0 0 0 98.00~102.00 1 0 0 0 0 0 102.00~111.00 0 0 0 0 0 0 111.00~ 0 0 0 0 0 0 � Go to cover page Forward Back Selftest check pin34 1.no H/V sync & first power ON - show msg. 2.H/V sync exist - normal 3.H/V sync non-exist & after power ON - power saving 4.Left+Right Keys pressed with IFcable - factory mode 5.left +Right Keys pressed without IF cable - burn in mode check idle status sda=pin36=hi scl=pin37=hi 36,37. DDC bus check idle status sda=pin38=hi scl=pin39=hi 38,39. IIC bus check keys ok,up,down,left,right 33. Keypad check pwm from 0V to 5V 4. Rotation check pwm from 0V to 5V 30. Brightness check 3319, 3891~3895 40,41. EEPROM write protection check pin40 pin41 write : low low read : don't care normal : hi hi check 7336 M24C16 7421 TDA4856 7781 LSC4389 7701 TDA4886A check from 5V to 0V 26, Reset check 6302/3322 2317/6301 check active=hi no active=low 1. Degauss 35. USB int pin35 hi : active low : no active Repair Flow Chart 45 109P2 GS3 CM25 � Go to cover page Forward Back 46 Repair Flow Chart F. TDA4856 Check List Basic check Vcc > 9V during startup 11.EWDRV 8. HDRV 14,15 Vsync,Hsync 12,13 Vout1/Vout2 inhibit pin6 output if pin3 is pulled to ground by 7508 a pin3 amplify pin5 and it compare to pin4 b. pin4 generate the saw_tooth wave c. pin5 input voltage for the square output waveform d. pin6 pwm output to 7422 & 7423 base pin16 CLBL=hi if no exist 3.4.5.6 B+ control 1. HFLB (from H.defl) to H_deflection. 7425&7426 base Vcc=pin10=12V gnd =pin7=pin25=0v Vertical blank will be activated = hi 1.pin30 = softstart pll2 = 0V 2.pin26 = pll1 is unlock in searching mode 3.pin1 = HFLB no exist 4.pin10 = Vcc < 9V 16. CLBL to B+ control east/west control differential input to 7567 pin 1, 7 the input sync from 7404 pin 14,15 109P2 GS3 CM25 � Go to cover page Forward Back 47 109P2 GS3 CM25 20 asymmetry EW output 30K 30 mm. V-shift range : total > 15 mm. 4.8 Display dimension stability Due to brightness : 1.0 % Due to aging : 1.0 % Due to mains voltage : 1.0 % Dynamic : < 1mm 4.9 Geometric distortions Pincushion, trapezoid, parallelogram, rotation and other various distortions must remain within the limits to tolerance as in Fig. 4. top/ bottom/left/ right : 2.5 mm Max. top plus bottom / left plus right : 3.5 mm Max. waviness : 1.5mm/ 50mm Max. slope change (Max) : one 65 109P2 GS3 CM25 GENERAL PRODUCT SPECIFICATION � Go to cover page Forward Back 8639 000 10535 00-08-01 JACK LIN 00-08-01 590 18 31 19" AUTO SCAN CMTR TYPE : 109P20/00C-CM25+109P2 BRAND : PHILIPS 4.10 Picture tilt ± 1mm (see Fig. 3) User adjust range for tilt : 1 deg. min. 4.11 Image non-linearity Horizontal: Max. - Min. x 100 % ? 8 % (30 - 31.5 KHz) Max. + Min. ? 7 % (31.6 - 64.0 KHz) ? 5 % (64.1 - 110 KHz) For any two adjacent blocks ? 5 % (30 - 31.5 KHz) ? 4 % (31.6 - 64.0 KHz) ? 3 % (64.1 - 111 KHz) Vertical : ¡ Ü5 % For any two adjacent blocks ? 3 % 4.12 Misconvergence The maximum convergence error should be measured on a white line and represents the maximum distance between the center of the red, green and blue lines over the whole image area. Max. misconvergence : 0.15 mm in C zone ( Picture area 355X265 See Fig. 6 ) 0.30 mm in A zone 0.40 mm in B zone 4.13 Focus check First, adjust brightness to 50 % position and contrast to max., and then generate "@" characters for 1024 lines to cover entire picture area (picture size is shown in sect. 4.5). Characters should be clearly identified at the center and all corners. Character size is shown in Fig. 7. 4.14 Brightness uniformity With an active video area full white pattern adjusted to 20 - 22 foot lambert, no portion of the pattern shall be less than 75 % of the luminance measured at the CRT center. 66 109P2 GS3 CM25 GENERAL PRODUCT SPECIFICATION � Go to cover page Forward Back 8639 000 10535 00-08-01 JACK LIN 00-08-01 590 19 31 19" AUTO SCAN CMTR TYPE : 109P20/00C-CM25+109P2 BRAND : PHILIPS 4.15 White color adjustment There are three factory preset white color 9300°K, 6500°K and 5500°K. Apply full white pattern, with brightness in 50 % position and the contrast control at max. position. The 1931 CIE Chromaticity (color triangle) diagram (x,y) coordinate for the screen center should be: 9300°K CIE coordinates X = 0.283 ± 0.020 Y = 0.297 ± 0.020 6500°K CIE coordinates X = 0.313 ± 0.020 Y = 0.329 ± 0.020 5500°K CIE coordinates X = 0.332 ± 0.020 Y = 0.347 ± 0.020 4.16 White uniformity Set the brightness control at center 50 % position, then adjust the contrast control to set the luminance at the center of the screen being in the range of 20 - 22 ft-lb. The color coordinate at any point on the screen should be : X = X (center) ± 0.015 Y = Y (center) ± 0.015 4.17 Color tracking on full white pattern Adjust the contrast control from max. to min.(with brightness at click position). The color coordinates should not deviate more than: x = x (center) +/- 0.015 y = y (center) +/- 0.015 4.18 Purity Conditions: With full color pattern, with brightness control at 50 % position and contrast control in maximum, under the specific destinations of earth magnetic environments. After a warm-up time of 30 min., the purity control can be used to eliminate colored stains if it occurs, the monitor should be well degaussed before purity adjustment. Remark: If the external degaussing is used, the degaussing coil should be a stick type, can’t use ring type for MITSUBISHI NF CRT. To set the electrical current of four corner purity coils and N/S coil (if exist) equal to zero, or switch off the monitor before external degaussing. 67 109P2 GS3 CM25 GENERAL PRODUCT SPECIFICATION � Go to cover page Forward Back 8639 000 10535 00-08-01 JACK LIN 00-08-01 590 20 31 19" AUTO SCAN CMTR TYPE : 109P20/00C-CM25+109P2 BRAND : PHILIPS 5.0 Mechanical characteristics 5.1 Controls Front side : - AC power switch - OSD function key Rear : - D- sub / BNC - Power cord socket 5.2 Unit dimension / Weight Set dimension (incl. pedestal) : 456(W) x 467(H) x 437.6(D) mm Net weight : 24.5 ¡ Ó0.5 Kg 5.3 Tilt and swivel base The display should be equipped with a tilt & swivel device allowing rotation over an angle of 90 degree left or rightward and for a tilt of -5 degree to +15 degree with respect to the horizontal position. 5.4 Transportation packages 5.4.1 Shipping dimension/Weight Carton dimension : 557(W) x 627(H) x 596(D) mm Gross weight : 28 .0 ¡ Ó0.5Kg 5.4.2 Block unit / Palletization layers/block sets/layer sets/block unit 3 4 12 blocks/container 20 feet 40 feet 8 20 6.0 Environmental characteristics The following sections define the interference and susceptibility condition limits that might occur between external environment and the display device. 68 109P2 GS3 CM25 GENERAL PRODUCT SPECIFICATION � Go to cover page Forward Back 8639 000 10535 00-08-01 JACK LIN 00-08-01 590 21 31 19" AUTO SCAN CMTR TYPE : 109P20/00C-CM25+109P2 BRAND : PHILIPS 6.1 Susceptibility of display to external environment Operating - Temperature : 0 to 35 degree C - Humidity : 10 to 90% (w/o condensation) - Altitude : 10,000 ft Storage - Temperature : -40 to 60 degree C - Humidity : 5 to 95% (w/o condensation) - Altitude : 40,000 ft - Condensation : should be prevented 6.2 Transportation tests European version USA version Standard Philips UAN-D1400 NSTA Height 50cm 45cm 1 corner 1 corner Drop Sequence 3 faces 3 edge Test 6 face electrical function ok Test mechanical function ok Result no serious damage on set appearance (room temp./-10°c, humidity 70 %) 7 HZ 5-100-5 Hz Sequence 1.05 G 0.5 G 30 min. for 15 min. for Vibration each axis each axis Test Test electrical function ok Result mechanical function ok no serious damage on set appearance For design evaluation only Operating 10 G, 16 msec, 1000 cycles, z-axes Bump pulse : half sine Test temperature : 23°C humidity : 60 % air pressure : 100 kpa (according to DSD draft standard UAN-D636) 69 109P2 GS3 CM25 GENERAL PRODUCT SPECIFICATION � Go to cover page Forward Back 8639 000 10535 00-08-01 JACK LIN 00-08-01 590 22 31 19" AUTO SCAN CMTR TYPE : 109P20/00C-CM25+109P2 BRAND : PHILIPS 6.3 Display disturbances from external environment According to IEC 801-2 for ESD disturbances 6.4 Display disturbances to external environment 6.4.1 Ionizatic radiation Completely fulfilled International Commission of Radiological Protection (ICRP) requirement 0.5 mR/hrs. 7.0 Reliability 7.1 Mean Time Between Failures MTBF to be calculated according to military standard MIL-HDBK-217C. MTBF > = 75,000 hrs (excluding CRT ) Total hrs (power on) x Total sets Practice of MTBF = NO. of failed sets 8.0 Quality assurance requirements 8.1 Acceptance test according to MIL-STD-105D Control II level AQL : 0.65 (major) 2.50 (minor) (please also refer to annual quality agreement) Customer acceptance criteria : UAW0377/00 9.0 Serviceability The serviceability of this monitor should fulfill the requirements which are prescribed in UAW-0346 and must be checked with the check list UAT-0361. 70 109P2 GS3 CM25 GENERAL PRODUCT SPECIFICATION � Go to cover page Forward Back 8639 000 10535 00-08-01 JACK LIN 00-08-01 590 23 31 19" AUTO SCAN CMTR TYPE : 109P20/00C-CM25+109P2 BRAND : PHILIPS 351 359 355 261 265 269 FIG-1 IMAGE DIMENSION m m m m m m m m m m m m 71 109P2 GS3 CM25 GENERAL PRODUCT SPECIFICATION � Go to cover page Forward Back 8639 000 10535 00-08-01 JACK LIN 00-08-01 590 24 31 19" AUTO SCAN CMTR TYPE : 109P20/00C-CM25+109P2 BRAND : PHILIPS FIG-2 IMAGE CENTERING 355 265 |A-B| AND |C-D| < 6 mm mm mm C D A B 72 109P2 GS3 CM25 GENERAL PRODUCT SPECIFICATION � Go to cover page Forward Back 8639 000 10535 00-08-01 JACK LIN 00-08-01 590 25 31 19" AUTO SCAN CMTR TYPE : 109P20/00C-CM25+109P2 BRAND : PHILIPS FIG-3 IMAGE ROTATION 265 1 1 355 mm mm mm mm 73 109P2 GS3 CM25 GENERAL PRODUCT SPECIFICATION � Go to cover page Forward Back 8639 000 10535 00-08-01 JACK LIN 00-08-01 590 26 31 19" AUTO SCAN CMTR TYPE : 109P20/00C-CM25+109P2 BRAND : PHILIPS FIG-4 IMAGE GEOMETRY 355 265 mm mm B A A = B = 2.5 mm 74 109P2 GS3 CM25 GENERAL PRODUCT SPECIFICATION � Go to cover page Forward Back 8639 000 10535 00-08-01 JACK LIN 00-08-01 590 27 31 19" AUTO SCAN CMTR TYPE : 109P20/00C-CM25+109P2 BRAND : PHILIPS 100 265 355 100 FIG-5 BRIGHTNESS AND CONTRAST mm mm mm MEASUREMENT AREA ZONE-B ZONE-A mm 75 109P2 GS3 CM25 GENERAL PRODUCT SPECIFICATION � Go to cover page Forward Back 8639 000 10535 00-08-01 JACK LIN 00-08-01 590 28 31 19" AUTO SCAN CMTR TYPE : 109P20/00C-CM25+109P2 BRAND : PHILIPS FIG-6 MISCONVERGENCE 355 265 mm mm ZONE C ZONE A ZONE B 76 109P2 GS3 CM25 GENERAL PRODUCT SPECIFICATION � Go to cover page Forward Back 8639 000 10535 00-08-01 JACK LIN 00-08-01 590 29 31 19" AUTO SCAN CMTR TYPE : 109P20/00C-CM25+109P2 BRAND : PHILIPS Fig 7 CHARACTER FORMAT FOR FOCUS CHECK 7 6 5 4 3 2 1 0 LINE HEX.DATA 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 2 2 E 2 2 0 C C C 2 3 3 3 4 4 4 4 5 5 5 5 5 6 7 8 9 A B C D E F 1 BYTE = 8BITS 77 109P2 GS3 CM25 GENERAL PRODUCT SPECIFICATION � Go to cover page Forward Back 8639 000 10535 00-08-01 JACK LIN 00-08-01 590 30 31 19" AUTO SCAN CMTR TYPE : 109P20/00C-CM25+109P2 BRAND : PHILIPS D VIDEO C E SEPARATE SYNC. HORIZONTAL B A R VIDEO Q S P O D VIDEO C E B A VERTICAL HORIZONTAL COMPOSITE SYNC. FIG-8 TIMING CHART -1 78 109P2 GS3 CM25 GENERAL PRODUCT SPECIFICATION � Go to cover page Forward Back 8639 000 10535 00-08-01 JACK LIN 00-08-01 590 31 31 19" AUTO SCAN CMTR TYPE : 109P20/00C-CM25+109P2 BRAND : PHILIPS VIDEO VERTICAL FIG-9 TIMING CHART -2 O P Q R S Safety Checks Fire and Shock H azard Implosion X-radiation After the original swevice problem has been corrected,a complete safety check should be made. Be sure to check over the entire set, not just the areas where you have worked. Some previous servicer may have left an unsafe condition,which could be unknowingly passed on to your customer. Be sure to check all of the following: 1. Be sure all components are positioned in such a way as to avoid the possibility of adjacent component shorts. This is especially important on those chassis which are transported to and feom the service shop. 2. Never release a repaired unit unless all protective devices such as insulators, barries, covers, strain reliefs, and other hardware have been installed in accordance with the original design. 3. Soldering and wiring must be inspected to locate possible cold solder joints,solder splashes,sharp solder points, frayed leads, pinched leads, or damaged insulation ( including the ac cord).Be certain to remove loose solder balls and all other loose foreign particles. 4. Check across-the-line components and other components for physical evidence of damage or deteriortion and replace if necessary. Follow original layout,lead length, and dress. 5. No lead or component should touch a receiving tube or a resistor rated at 1 watt or more. Lead tension around protruding metal surfaces or edges must be avoided. 6. Critical components having special safety characteristics are identified with ans bythe Ref. No. in the parts list and enclosed within a broken line * (where seceral criticalcomponents are grouped in one area) along with the safety symbols on the schematic diagrams and/or exploded views. 7. When servicing any unit, always use a seoparate isolation transformer for the chassis Failure to use a separate isolation transformer may exopose you to possible shock hazard, and may cause damage to servicing instruments. 8. Many electronic products use a polarized ac line cord (one wide pin on the plug.) Defeating this safety feature may create a potential hazard to the service and the user. Extension cords which do not incorporate the polarizing feature should never be used. 9. After reassembly of the unit, always perform an leakage test or resistance test from the line cord to all exposed metal parts of the cabinet. Also check all metal control shafts(with knobs removed), antenna terminals, handles, screws, etc. to be sure the unit may be safety operted without danger of electrical shock. * Broken line 1. All picture tubes used in current model receivers are equipped with an intergral implosion system. Care should always be used, and safety glassesworn,whenever handling any picture tube. Avoid scratching or other rwise damaging the picture tube during installation. 2. Use only replacement tubes specified by the manufacturer. 1. Be sure procedures and instructions to all your service personnel cover the subject of X-radiation. Potential sources of X-rays in TV receivers are the picture tube and the high voltage circuits. The basic precaution which must be exercised is to keep the high voltage at the factory recommended level. 2. To avoid possible exposure to X-radiation and electrical shock, only the manufacturer's specified anode connectors must be used. 3. It is essential that the service technician has an accurate HV meter available at all times. The calibration of this meter should be checked periodically against a reference standard. 4. When the HV circuitry isoperating properly there is no possibility of an x- radiation problem. High voltage should always be kept at the anufacture,s rated value-no higher - for optimum performance. Every time a color set is serviced, the brightness should be run up and down while monitoring the HV with a meter to be certain that the HV is requlated correctlv and does not exceed the specified value. We suggest that you and your technicians review test procedures so that HV requation are always checked as a standard servicing procedure, and the reason for this prudent routine is cleary understood by everyone. It is important to use an accurate and reliable HV meter. It is recommended that the HV recorded on each customer's invoice, which will demonstrate a proper concern for the customer's safety. 5. When troubleshooting and making test measurements in a receiver with a problem of excessive high voltage, reduce the line voltage by means of a Variac to bring the HV into acceptable limits while troubleshooting. Do not operate the chassis longer than necessary to locate the cause of the excessive HV. : : WSRNING OFF SERVICE NOTE Before removing the CRT anode cap, turn the unit and short the HIGH VOLTAGE to the CRT DAG ground. The CRT DAG is not at chassis ground. TELEVISION/MONITOR SAFETY GUIDELINES FOR THE PROFESSIONAL SERVICE TECHNICIAN 6. New picture tubes are specifically designed to withstand higher operathng voltages without creating undesirable X-radiation. It is strongly recommended that any shop test fixture which is to be used with the new higher voltage chassis be equipped with one of the new type tubes designed for this service.Addition of a permanently connected HV meter to the shop test fixture is advisable. The CRT types used in these new sets should never be replaced with any other types,as this may result in excessive X-radiation. 7. It is essential to use the specified picture tube to avoid a possible X-diation problem. 8. Most TV receivers contain some type of emergency "Hold Down" circuit to pervent HV from rising to excessive levels in the presence of a failure mode. These various circuits should be understood by all technicians servicing them, especially since many hold down circuits are inoperative as long as the receiver performs normally. 1. Unplug the ac line cord and connect a jumper between the two prongs of the plug. 2. Turn on the power switch. 3. Measure the resistance value between the jumpered ac plug and all exposed cabinet parts of the receiver, such as screw heads, antennas, and control shafts.When the exposed metallic part has a return path to the chassis, the reading should be between 1 megohm and 5.2 megohms. When the exposed metal does not have a return path to thr chassis, the reading must be infinity.Remove the jumper from the ac line cord. 1. Do not use an isolation transformer for this test. Plug the completely reassembled receiver directly into the ac outlet. 2. Connect a 1.5k, 10w resistor paralleled by a 0.15uf. capacitor between each exposed metallic cabinet part and a good earth ground such as a water pipe, as shown above. 3. Use an ac voltmeter with at least 5000 ohmsy volt sensitivity to measure the potential across the resistor. 4. The potential at any point should not exceed 0.75 volts. A leakage current tester may be used to make this test; leakage current must not exceed 0.5 milliamps. If a measutement is outside of the specified limits, there is a possibility of shock hazard. The receiver should be repaired and rechecked before retutning it to the customer. 5. Repeat the above procedure with the ac plug reversed.( Note: An ac adapter is necessary when a polarized plug is used. Do not defeat the polarizing feature of the plug.) The primary source of X-radiation in this television receiver is the picture tube.The picturetube utilized in this chassis is specially constructed to limit X-radiation emissions. For continued X-radiation protection, the replacement tube must be the same type as the original, including suffix letter,or a Philips approved tupe. Many electrical and mechanical parts in Philips television sets have special safety related charcteristics. These characteristics are often not evident from visual inspection nor can the protection afforded by them necessarily be obtained by using replacement components rated for higher voltage, wattage, etc. The use of a substitute part which does not have the same safety characteristics as the Philips recommended replacement part shown in this service manual may create shock, fire, or other hazards Leakage Current Cold Check Leakage Current Hot Check Picture Tube Replacement Parts Replacement 1500 ohm, 10W 0.15 uF WATER PIPE EARTH GROUND TO INSTRUMENTS EXPOSED METAL PARTS � Go to cover page
