1 维 修 手 册 客户/品牌 机种名 AOC 931Sn SERVICE MANUAL 2 变更说明 版本 发布日期 变更说明 对外机种名 对内机种名 T89GHDNDW5A3NNE T89CHDNDW5A4NNE A00 Jan.-14-2010 Initial Release 931Sn T89AHDNDW5A4NNE 3 目录 1. 技术规格 -------------------------------------------------------------------------------------------------------------- 4 1.1 一般规格 --------------------------------------------------------------------------------------------------------- 4 1.2 工厂预设模式 --------------------------------------------------------------------------------------------------- 5 2. 操作说明 -------------------------------------------------------------------------------------------------------------- 6 2.1 控制面板--------------------------------------------------------------------------------------------------------- 6 2.2 接口说明--------------------------------------------------------------------------------------------------------- 7 2.3 OSD 菜单调整 ------------------------------------------------------------------------------------------------- 8 3. 工厂模式调整 -------------------------------------------------------------------------------------------------------- 11 4. 故障处理流程 -------------------------------------------------------------------------------------------------------- 12 4.1 主板--------------------------------------------------------------------------------------------------------------- 12 4.2 电源板------------------------------------------------------------------------------------------------------------ 15 4.3 按键板------------------------------------------------------------------------------------------------------------ 17 5. 电气方框图 ----------------------------------------------------------------------------------------------------------- 18 5.1 主板--------------------------------------------------------------------------------------------------------------- 18 5.2 电源板------------------------------------------------------------------------------------------------------------ 19 6. 线路图 ----------------------------------------------------------------------------------------------------------------- 20 6.1 主板--------------------------------------------------------------------------------------------------------------- 20 6.2 电源板------------------------------------------------------------------------------------------------------------ 24 7. 料件清单 -------------------------------------------------------------------------------------------------------------- 26 4 1.技术规格 1.1 一般规格 产品代码 931Sn 驱动系统 TFT 彩色 LCD 可视尺寸 47.0cm 对角 像素间距 0.3mm(H) x 0.3mm(V) 视频 R, G, B 模拟接口 独立同步 行 /场 TTL 显示颜色 16.7M 色彩 LCD 面板 点时钟 85.5 MHz 水平扫描范围 30 kHz - 81 kHz 水平扫描尺寸（最大） 409.8mm 垂直扫描范围 55 Hz - 75 Hz 垂直扫描尺寸（最大） 230.4mm 预设的最佳分辨率 1366 x 768 (60 Hz) 预设的最高分辨率 1366 x 768 (60 Hz) 即插即用 VESA DDC2B/CI 输入连接器 D-Sub 15 针 输入视频信号 模拟： 0.7Vp-p（标准），75 OHM 电源 100-240VAC, 50/60Hz 开机 < 25 W 分辨率 功率消耗 离机 < 1 W 连接器类型 15- 针 Mini D-Sub 信号电缆类型 可分离 尺寸和重量： 高度 (含底座) 357.9 mm 宽度 455.2mm 深度 219.7mm 重量（仅监视器） 3.53kg 物理 特性 重量（含包装） 4.86 kg 温度 工作时 0°- +40° 非工作时 -20°- +60° 湿度： 工作时 10% - 85%（非凝露） 非工作时 5% - 80%（非凝露） 海拔高度 工作时 0~3000m (0~10000 ft) 环境 非工作时 0~5000m (0~15000 ft) 5 1.2 工厂预设模式 标准 分辨率 水平频率(kHZ) 垂直频率(Hz) VGA 640 x 480 @60Hz 31.469 59.94 VGA 640 x 480 @67Hz 35 66.667 VGA 640 x 480 @72Hz 37.861 72.809 VGA 640 x 480 @75Hz 37.5 75 Dos-mode 640 x 400 @70Hz 31.469 70.087 Dos-mode 720 x 400 @70Hz 31.469 70.087 SVGA 800 x 600 @56Hz 35.156 56.25 SVGA 800 x 600 @60Hz 37.879 60.317 SVGA 800 x 600 @72Hz 48.077 72.188 SVGA 800 x 600 @75Hz 46.875 75 Mac-mode 832 x 624 @75Hz 49.725 74.5 XGA 1360 x 768 @60Hz 47.712 60.015 XGA 1024 x 768 @60Hz 48.363 60.004 XGA 1024 x 768 @70Hz 56.476 70.069 XGA 1024 x 768 @72Hz 57.5 72.074 XGA 1024 x 768 @75Hz 60.023 75.029 XGA 1024 x 768 @75Hz 60.241 74.927 WSXGA 1366 x 768 @60Hz 47.765 59.85 6 2.操作说明 2.1 控制面板 外部控制 按电源开关即可开关显示器。其它功能按键位于前面板下方 。通过调节这些功能键可得到您需要的画面。 * 接好电源线。 * 将信号线接到 PC 机显卡。 * 打开显示器把开关打到开机位置，电源指示灯亮。 1 亮度情景模式(动态对比度) / - 2 4:3/宽屏切换 /+ 3 电源开关 4 自动调整 / 退出 5 菜单键/选择 7 2.2 接口说明 管脚号 信号电缆的 15 针一端 管脚号 信号电缆的 15 针一端 1 视频 - 红色 9 +5V 2 视频 - 绿色 10 接地 3 视频 - 蓝色 11 接地 4 接地 12 DDC- 串行数据 5 检测电缆 13 H- 同步 6 GND-R 14 V- 同步 7 GND-G 15 DDC- 串行时钟 8 GND-B 8 2.3 OSD 菜单调整 • 按 MENU 按钮激活 OSD 窗口。 • 按 + 或 - 浏览这些功能。 如果想要调整的功能突出显示，按 MENU 按钮激活它。如果所选的功能包含有 子菜单，再按一下 + 或 - 可以浏览到子菜单功能。如果想要调整的功能突出显示，按 MENU 按钮激活它。 • 按 + 或 - 更改所选功能的设置。要退出和保存，请选择退出功能。 • 如果您想调整其它任何功能，请重复步骤 2-3 。 • OSD 锁定功能： 要锁定 OSD ，请在显示器关闭时按住 MENU 按钮，然后按电源按钮打开显示器。 要解 锁 OSD ，请在显示器关闭时按住 MENU 按钮，然后按电源按钮打开显示器 。 • 亮度情景模式及动态对比度热键： 在画面没有 OSD 时，连续按此热键可选择不同的亮度情景应用模式及打 开动态对比度功能。 • 4:3 及宽屏画面切换热键 : 在画面没有 OSD 时, 连续按此键可进行 4:3 或宽屏显示模式切换(如果产品屏幕尺 寸是 4:3 或者输入信号的分辨率是宽屏模式时, 此键无作用)。 • 自动调整快捷键: 当没有 OSD 菜单时, 按自动调整快捷键可启动自动调整功能。 功能控制说明. 明亮度 调整数值 说明 亮 度 0-100 调整显示亮度 对比度 0-100 调整显示对比度 标准 正常使用模式 Eco Mode 节能 文本应用模式 9 网络 网络应用模式 游戏 游戏应用模式 电影 观赏电影应用模式 运动 观赏户外运动模式 伽玛 1 调整为伽玛值 1 伽玛 2 调整为伽玛值 2 伽玛 伽玛 3 调整为伽玛值 3 关闭 关闭动态对比度 DCR 开启 开启动态对比度 图象设置 时钟 0-100 调整图片时钟以降低垂直线噪声 相位 0-100 调整图片相位以降低水平线噪声 水平位置 0-100 调整图片的水平位置 垂直位置 0-100 调整图片的垂直位置 色温 暖色 6500K 设置为暖色温 正常 7300K 设置为正常色温 冷色 9300K 设置为冷色温 sRGB 设置为 sRGB 红 微调红色色温 绿 微调绿色色温 用户设定 蓝 微调蓝色色温 色彩增强 全色增强 关闭/开启 开启或关闭全色增强模式 自然肤色 关闭/开启 开启或关闭自然肤色模式 绿茵场景 关闭/开启 开启或关闭绿色增强模式 蔚蓝风景 关闭/开启 开启或关闭蓝色增强模式 自动检测 关闭/开启 开启或关闭自动增强模式 演示 关闭/开启 开启或关闭左画面演示 窗口增亮 窗口尺寸 14-100 调整窗口尺寸大小 亮 度 0-100 调整窗口亮度 10 对比度 0-100 调整窗口增强对比度 水平位置 0-100 调整水平窗口位置 垂直位置 0-100 调整垂直窗口位置 增亮 关闭/开启 开启或关闭增亮窗口 OSD 设置 水平位置 0-100 调整 OSD 水平位置 垂直位置 0-100 调整 OSD 垂直位置 显示时间 5-120 调整 OSD 显示时间 透明度 0-100 调整 OSD 透明度 语言 选择 OSD 语言 其它 输入选择 模拟 选择输入为模拟信号源 自动调整 是或者否 自动调整画面 画面比例 宽屏或 4:3 选择宽屏或 4:3 显示格式 DDC-CI 是或者否 打开/关闭 DDC-CI 支持 定时关机 0~24 小时 设定显示器关机时间 显示信息 显示输入信号信息 重置 重置 是或者否 恢复到出厂设置 退出 退出 退出 OSD LED 指示灯 状态 LED 颜色 开机模式 绿色或蓝色 离机模式 橙色或红色 11 3.工厂模式调整 进入工厂模式方法： 机器应处于开机状态，关断输入的220V电源，按住Menu键，然后接通电源，工厂模式菜单将位于屏的左上角。 a.基本调整: 设置对比度 为 50。 设置亮度 为 90。 b.增益调整: 调整9300K色温 1、选中“AUTO LEVEL”先进行底光栅自动调整 2、按“MENU”选择9300K进行R G B增益调整 x = 283 ±30, y = 297 ±30, Y = 180 ±30 cd/m2 调整7300K色温 1、选中“AUTO LEVEL”先进行底光栅自动调整 2、按“MENU”选择7300K进行R G B增益调整 x = 302 ±30, y = 318 ±30, Y = 180 ±30 cd/m2 调整6500K色温 1、选中“AUTO LEVEL”先进行底光栅自动调整 2、按“MENU”选择 6500K 进行 R G B 增益调整 x = 313 ±30, y = 329 ±30, Y = 180 ±30 cd/m2 调整sRGB色温 1、选中“AUTO LEVEL”先进行底光栅自动调整 2、按“MENU”选择 sRGB 进行 R G B 增益调整 x = 313 ±30, y = 329 ±30, Y = 180 ±30 cd/m2 c.调整完毕直接关闭电源。 12 4.故障处理流程 4.1 主板 无供电 无供电 按下电源键看画面是否正常 重新插插头然后检查 AC:100-240V 是否正常? 检查 U404 Pin2=3.3V; U405 Pin2=1.8V 检查适配器及升压板部分和交流电源输入 检查 X401 晶振是否正常 检查或更换 CN404,U404,U405 更换 U401 更换 X401 OK OK OK NG NG NG NG 13 无画 (LED 橙色) 无画 检查信号线 更换信号线 检查 U404 Pin2=3.3V; U405 Pin2=1.8V 更换 U401 检查 X401 震荡波是否正常 更换 CN404,U404,U405 OK OK OK OK NG NG 检查 CN101 的 HS/VS 是否正常 更换 X401 检查相关回路 NG NG 14 白屏 白屏 检查 Q404 的基极是否 为低电平 检查 X401 的晶振是否正常 检查 FB402 是否损坏或 CN403 虚焊 检查相关元件 更换 PANEL 检查相关元件 更换 U401 OK OK OK 更换 X401 OK NG NG NG NG 检查 U401 复位电路是否正常 15 4.2 电源板 死机 检测交流电 100V or 240V 是否正常？ 检测 AC 输入 检测 C907 (+)的电压大小 检测全桥整流回路和 F901 回路 检测 IC901 第 8 脚电压是否正常？ 检测 R904, R932 或更换 IC901 NG 检测二次启动电压是否正常？ 1) 检测 IC901 2) 检测 D903 回路 检测 D905,D906,D907,Q901,IC903,ZD902 OK 检测 IC901 第 5 脚的 PWM 波形 OK 检测 IC901 NG NG OK OK OK NG NG 16 无背光 检测 C802(+)电压是否为12V NG OK 检测 Adapter 回路 检测 ON/OFF 信号 检测主板 NG OK 检测 IC801 第 12 脚是否为 12V NG OK 检测 IC801 第 9/10 脚的 PWM 波形 NG 检测 T801 的输出 检测 Q802 检查接口或灯管,反馈和保护回路 OK NG 更换 T801 OK 更换 IC801 17 4.3 按键板 OSD 画面不稳定及不可调整 OK OSD 画面不稳定及不可调整 按键板是否连接正常 连接好按键板 按键开关是否正常 替换按键开关 OK NG NG 按键板是否正常 替换按键板 OK NG OK 检查主板 18 5.电气方框图 5.1 主板 Crystal 24.576MHz (X401) FLASH ROM SST25LF020A (U402) Scalar IC HX6803-A000LAG (Include ADC, OSD, MCU) (U401) D-Sub Connector (CN101) Panel Interface (CN403) EEPROM M24C04 (U406) Key Control Interface (CN408) 19 5.2 电源板 Feedback Circuit Transformer (T801) MOSFET (Q802) Lamp Output Circuit PWM Control IC TL494IDR (IC801) ON/OFF DIM 12V EMI filter Start Circuit (R904,R932) PWM Control IC LD7575A PS (IC901) Transformer (T901) 12V 5V Bridge Rectifier,Filter Rectifier diodes Power Switch (Q901) Regulator (IC903) 20 6.线路图 6.1 主板 R125 4K7 1/16W 5% VGA_PLUG OEM MODEL Size Rev Date Sheet of TPV MODEL PCB NAME 称爹 T P V ( Top Victory Electronics Co . , Ltd. ) Key Component 絬 隔 瓜 絪 腹 AOC 931SN D TBD B 2 5 Monday , September 21, 2009 G2681-1-4 <称爹> 02.Input G2681-1-4-X-1-090921 U101 M24C02-WMN6TP A0 1 A1 2 A2 3 VSS 4 SDA 5 SCL 6 WP 7 VCC 8 C120 10pF B_GND 5V_ESD C121 10pF DSUB_SCL DSUB_SDA 候綼　U103 G_GND DSUB_5V CMVCC1 DSUB_5V 5 CMVCC1 5 C122 10pF R_GND C110 0.047uF VGA_R+ VGA_B+ VGA_G+ EDID_WP V_Sy nc C118 0.1uF/16V D105 BAV70 3 1 2 候綼　U101 R121 10K 1/16W 5% R120 10K 1/16W 5% R119 4K7 1/16W 5% DDC1_SCL 3 DDC1_SDA 3 DSUB_V 3 DSUB_H 3 DSUB_B+ 3 DSUB_SOG 3 DSUB_R+ 3 DSUB_G+ 3 DET_CABLE 3 DDC1_SDA DDC1_SCL EDID_WP H_Sy nc Q410 2N3904S-RTK/PS FB104 300 OHM VGA_G+ B_GND H_Sy nc V_Sy nc G_GND VGA_B+ R_GND VGA_B+ DSUB_5V VGA_R+ VGA_G+ VGA_R+ DSUB_SDA DSUB_SCL VGA_PLUG C106 0.047uF U102 AZC099-04S I/O1 1 GND 2 I/O2 3 I/O3 4 VDD 5 I/O4 6 R110 100R 1/16W 5% ZD104 UDZSNP5.6B 1 2 U103 AZC099-04S I/O1 1 GND 2 I/O2 3 I/O3 4 VDD 5 I/O4 6 R124 CHIP BEAD R122 CHIP BEAD R112 75R 1/16W 5% R103 1K 1/16W 5% C115 NC R101 80 OHM CN101 DB15 1 6 2 7 3 8 4 9 5 11 12 13 14 15 10 17 16 R107 75R 1/16W 5% R109 390 OHM 1/16W R113 100R 1/16W 5% R118 1K 1/16W 5% R111 390R 1/16W 5% C114 NC C101 0.047uF C102 22pF C107 0.047uF R115 390R 1/16W 5% R102 1K 1/16W 5% R123 CHIP BEAD R105 2K2 1/16W 5% R106 2K2 1/16W 5% R116 75R 1/16W 5% C103 22pF ZD103 UDZSNP5.6B 1 2 R104 390R 1/16W 5% DSUB_5V 5 VCC3.3 3,5 GND POWER DGND VCC3.3 DSUB_5V 5V_ESD ESD_5V DDC1_SDA DDC1_SCL 21 POWER_KEY# VCC3IO C438 0.1uF/16V C439 0.1uF/16V KEY1 SDO CSN SCK SDI GND RST PANEL_ID# 7 SDI CSN SCK SDO VCC3IO XTAL_OUT R469 0R05 1/16W R456 1K 1/16W 5% SPI_WP# VCC1.8 5 R468 NC VCC3.3 GND FB406 BEAD 1 2 OEM MODEL Size Rev Date Sheet of TPV MODEL PCB NAME 称爹 T P V ( Top Victory Electronics Co . , Ltd. ) Key Component 絬 隔 瓜 絪 腹 AOC 931SN D TBD Custom 3 5 Monday , September 21, 2009 G2681-1-4 <称爹> 03.Scaler G2681-1-4-X-1-090921 C442 10uF/10V VSSA_AD VSSP_AD GNDIO GNDIO adj_BACKLIGHT 5 Mute 5 VSSP_AD Volume# 5 R462 10K 1/16W 5% on_Panel 4 C441 10uF/10V on_BACKLIGHT 5 R461 10K 1/16W 5% GND R460 10K 1/16W 5% R471 100R 1/16W 5% R472 100R 1/16W 5% R473 100R 1/16W 5% USRD_MSCL C444 0.22UF 10V C455 10uF/10V DET_CABLE 2 VCC3.3 GND R480 NC R466 0R05 1/16W C450 0.1uF/16V R467 10K 1/16W 5% R465 6K8 1/16W 5% CMVCC USER DATA LVDS X1 GROUNG SHIELDING VCCK VCCLVP VCCP CMVCC 5 KEY2 綼　IC PIN 綼　IC PIN AC_DET UDP_WP KEY1 SPI_WP# VDDA_AD VCC3.3 C404 0.1uF/16V VSSP_AD C433 0.1uF/16V VDDP_AD POWER_KEY# POWER_KEY# PA4 PA5 PA[4..9] R419 NC/61G0402101 PA6 PA7 PA9 PA8 VCC3.3 2,5 USRD_MSDA LED_GRN/BLUE PB[0..9] PB1 PB0 PB4 PB2 PB3 PB5 SST-020A ZD401 NC/UDZSNP5.6B 1 2 KEY2 PB6 PB9 PB8 CN408 CONN 1 2 3 4 5 6 PB7 CN409 NC/CONN 1 2 3 4 5 6 7 VSSA_AD C436 0.1uF/16V C437 0.1uF/16V 1 AC_DET DSUB_B+ 2 DSUB_G+ 2 DSUB_SOG 2 DSUB_V 2 DSUB_H 2 DSUB_R+ 2 DDC1_SDA 2 DDC1_SCL 2 0 GND R402 1K6 OHM 1/16W 5% U406 M24C04-WMN6TP NC 1 E1 2 E2 3 VSS 4 SDA 5 SCL 6 WC 7 VCC 8 C409 0.1uF/16V VDDP_AD C405 0.01uF/25V 0 CMVCC R488 10K 1/16W 5% R487 10K 1/16W 5% CN406 NC/CONN 1 2 3 4 5 6 7 8 C401 0.1uF/16V R486 NC/1K 1/16W 5% C402 4.7uF/16V R455 1K 1/16W 5% R454 NC PA[4..9] 4 PB[0..9] 4 R401 1M 1/16W 5% Q412 2N3904S-RTK/PS VREF PA[0..1] CSN SDO SCK R463 NC R464 NC RST C456 1uF/16V R485 NC/1K PA0 POWER_ON_LATCH PA[0..1] 4 Near to Connect R450 5K1 OHM 1/16W 5% VDDP_AD VDDDP_AD VDDA_AD LED_ORANGE VCCLVP PA1 CN402 NC/CONN 1 2 3 4 5 6 VCCP X401 24.576MHz CN407 NC/CONN 1 2 3 4 5 6 7 Q402 PMBS3906 R427 3.9K OHM 1/16W C407 0.1uF/16V R407 10K 1/16W 5% C412 33pF FB404 NC Q401 PMBS3906 C411 33pF R428 3.9K OHM 1/16W R416 4K7 1/16W 5% R411 100R 1/16W 5% R421 10K 1/16W 5% C408 0.22uF16V C403 0.1uF/16V C445 NC C413 0.1uF/16V R410 120R 1/16W 5% TOUCH_POWER U402 SST25LF020A-33-4C-SAE CE# 1 SDO 2 WP# 3 VSS 4 SDI 5 SCK 6 HOLD# 7 VDD 8 R414 120R 1/16W 5% C417 0.1uF/16V C414 0.1uF/16V R420 100R 1/16W 5% C416 0.1uF/16V HX6803-A000LAG U401 VDDP_AD(3.3V) 13 VDDA_AD(3.3V) 10 HSYNC 11 SOG 8 VSYNC 12 R 9 G 7 VDDDP_AD(3.3V) 16 DDCA_SDA/RS232_TX/GPIO17 17 VREF(1.25V) 4 VSSP_AD 15 FILT 14 USRD_MSCL/GPIO16 21 CSN 23 SDO 22 SCK 24 GPIO02/RS232_RX 27 SAR1 56 XTAL_IN 1 VCCP(1.8V) 2 LVA2P 35 LVA2N 36 LVA1P 37 LVA1N 38 LVA0P 39 LVA0N 40 LVB3P 42 LVB3N 43 LVBCKP 44 LVBCKN 45 LVB2P 46 LVB2N 47 LVB1P 48 LVB1N 49 LVB0P 50 LVB0N 51 LVA3N 34 LVA3P 33 VSSA_AD 5 B 6 VCCK(1.8V) 32 GNDIO 31 VCCK(1.8V) 52 VCC3IO(3.3V) 30 DDCA_SCL/RS232_RX/GPIO18 18 GPIO00/PWMD 19 TSTMD 62 USRD_MSDA/GPIO15 20 GPIO03/PWMB 28 SAR0 55 PWMB/GPIO10 58 PWMC/GPIO11 59 PWMD/GPIO12 60 GPIO05 61 RST_N 63 XTAL_OUT 64 SDI 25 GPIO01/RS232_TX 26 VCC3IO(3.3V) 54 VCCLVP(1.8V) 41 GNDIO 53 GPIO04/PWMC 29 SAR2 57 GPIO06 3 C415 0.1uF/16V R415 4K7 1/16W 5% R418 NC/61G0402101 0 SCK PMC,MXIC(2M) 1 SST-010A R453 1K 1/16W 5% C406 0.1uF/16V 1 0 0 0 0 SST-010 0 CSN R452 NC R451 NC 1 PMC,MXIC(1M) Spansion(2M) POWER_ON_LATCH Setting R412 100R 1/16W 5% SPI-Flash 1 0 0 SDO 0 0 1 R404 10K 1/16W 5% R490 NC/61G0402101 VDDDP_AD VCC3.3 VCC3.3 VCC3.3 VCC3.3 VCC1.8 FB409 220OHM 1 2 VCCK VCC3.3 VCC3.3 LED_GRN/BLUE LED_ORANGE FB405 BEAD 1 2 TOUCH_POWER VCC3.3 R457 10K 1/16W 5% SPI_WP# R482 10K 1/16W 5% 22 PB2 Ripple Current NG PB4 PB5 PB0 PB6 LVDS OUTPUT on_Panel OEM MODEL Size Rev Date Sheet of TPV MODEL PCB NAME 称爹 T P V ( Top Victory Electronics Co . , Ltd. ) Key Component 絬 隔 瓜 絪 腹 AOC 931SN D TBD A4 4 5 Monday , September 21, 2009 G2681-1-4 <称爹> 04.Output G2681-1-4-X-1-090921 on_Panel 3 2 AO3401L 3 D G 1 S PANEL_VCC C446 NC/65G0402104 15 C447 NC PA1 PA0 R435 4K7 1/16W 5% + C421 100UF25V FB402 120OHM R436 51K OHM 1/16W Q404 PMBS3906 VCC3.3D 5 Q405 AO3401 C420 0.1uF/16V CN405 NC/33G801930F CH JS 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 R434 330 OHM 1/4W C419 0.1uF/16V R433 10K 1/16W 5% PANEL_VCC PANEL_VCC CMVCCD 5 PB9 PB8 PB7 PA[0..1] PB6 PA4 PA5 PA[4..9] PA6 PA7 PA9 PA8 PB5 PB4 PA1 PA[0..1] 3 PA[4..9] 3 PB3 PB[0..9] PB4 PB3 PB1 PB0 PB[0..9] 3 PB5 PB2 PB8 PB9 PB6 PB7 PB2 PB1 PB2 PB1 PB9 PA9 PA6 PA0 PA5 PA4 PB7 PA8 PB8 PB0 PA7 PB3 PB3 PA9 PA8 PA7 PA6 PA5 R481 47K 1/16W 5% PA4 PB3 CN403 CONN 2 4 6 8 10 12 14 16 18 20 22 24 26 28 30 1 3 5 7 9 11 13 15 17 19 21 23 25 27 29 PB2 PA1 PA0 23 U403 NC/AP1117D33LA ADJ(GND) 1 VOUT 2 VIN 3 VCC3.3D VCC3.3D 4 R478 NC Q411 2N3904S-RTK/PS R477 4K7 1/16W 5% PANEL_ID# VCC1.8 3 R441 1K 1/16W 5% Q408 2N3904S-RTK/PS D402 SR24 R447 NC C432 0.1uF/16V + C424 100uF M 16V + C426 100uF M 16V + C423 100uF M 16V R438 3.3 OHM 2W D401 NC/BAV70//93G 64 42 P 3 1 2 R440 4K7 1/16W 5% + C427 100uF M 16V R437 10K 1/16W 5% R446 NC/10K 1/16W 5% R439 10K 1/16W 5% Q406 2N3904S-RTK/PS U405 VI 3 VO 2 GND 1 VO 4 C425 NC U404 AP1117E33LA VSS 1 VOUT 2 VIN 3 4 4 R448 4.7K 1/16W C422 0.1uF/16V R449 NC C428 0.1uF/16V C431 0.1uF/16V MVCC CMVCC VCC3.3 VCC3.3 VCC3.3 VCC3.3 VCC3.3 VCC3.3 VCC1.8 CMVCC1 CMVCC1 DSUB_5V CMVCC1 OEM MODEL Size Rev Date Sheet of TPV MODEL PCB NAME 称爹 T P V ( Top Victory Electronics Co . , Ltd. ) Key Component 絬 隔 瓜 絪 腹 931SN D TBD B 5 5 Monday , September 21, 2009 G2681-1-4 <称爹> 05.POWER G2681-1-4-X-1-090921 D403 BAT54C R476 0R05 1/16W R491 NC BKLT_VBRI R475 10K 1/16W 5% Mute 3 adj_BACKLIGHT 3 Volume# 3 on_BACKLIGHT 3 CN404 CONN 1 2 3 4 5 6 7 8 9 FB408 NC,71G 56Z601 FB407 300 OHM CMVCCD 4 ESD_5V 2 Volume BKLT_EN BKLT_VBRI Mute BKLT_EN Volume CMVCC CMVCC CMVCC 3 CMVCC1 2 DSUB_5V 2 VCC3.3 2,3 ESD_5V 24 6.2 电源板 ZD902 RLZ13B 1 2 HS2 HEAT SINK(D906_Q90G6263-6) 1 2 D915 LL4148 T901 POWER X'FMR 7 8 9 10 11 12 4 5 6 1 2 D916 LL4148 +12V +5V F904 NC C912 0.001uF F902 NC ! R962 100 OHM 1/4W R920 100 OHM 1/4W R946 150 OHM 2W C910 NC R922NC R923NC D907 NC R921NC ! HS3 HEAT SINK(Q901_Q90G6263-6) 1 2 R938 10K 1/8W ! VAR901 Varistor C909 470pF/25V R910 10R 1/4W ! R914 0.47 OHM +-5% 2WS R912 220 OHM 1/4W ! ZD905 RLZ18B 1 2 R927 3.6K OHM 1% 1/10W C902 1000pF ! t NR901 NTCR F903 NC R909 5.1 OHM 1/4W ! R930 2.43K OHM 1% 1/10W C928 0.01uF GND1 GND 1 2 ! ! C911 0.1uF + C907 82uF 450V D901 FR103 R904 10K OHM 1/4W L905 NC R908 100KOHM +-5% 2WS D900 FR107 C901 1000pF R915 100K OHM 1% 1/8W R925 1K 1/8W + C921 NC ! R940 33K 1/10W ZD921 RLZ13B 1 2 R942 1K 1/10W 1% ZD922 RLZ5.1B 1 2 D903 LL4148 ZD923 NC 1 2 HS5 SHIELD(H85G0002-1) 1 2 +5V1 C932 0.001uF R939 1K 1/8W Q903 PMBS3904 R943 470R 1/8W Q901 2SK2645-54MR + C939 NC N.C F905 0 OHM 1/4W ! ! C938 NC C906 1500pF2KV ! R900 680K OHM 1/4W R902 680K OHM 1/4W R901 680K OHM 1/4W R932 10K OHM 1/4W ! ! ! + C940 1000uF16V C930 0.1uF ! R948 NC C908 0.22UF IC902 PC123X2YFZOF 1 2 4 3 R924 150R 1/8W + C917 680uF/25V D905 31DQ06FC3 + C915 470uF/16V IC903 AZ431AZ-AE1 R961 100 OHM 1/4W R935 100 OHM 1/4W + C903 22uF/50V L903 1.0uH Q904 NC C929 0.001uF R952 NC L901 30mH 1 4 2 3 C925 NC CN901 87G 501 32 S SOCKET 1 2 3 R947 NC R918 100 OHM 1/4W R919 100 OHM 1/4W C924 0.1uF C900 3300pF 250V R907 NC F19S R926 1K 1/10W 1% R906 NC R905 NC +5V C931 0.1uF CN902 CONN 1 2 3 4 5 6 7 8 9 10 ON/OFF DIM MUTE VOL L904 1.0uH OEM MODEL Size Rev Date Sheet of TPV MODEL PCB NAME 称爹 T P V ( Top Victory Electronics Co . , Ltd. ) Key Component 絬 隔 瓜 絪 腹 PWPC9821GHD1 A Custom 2 4 Tuesday , August 18, 2009 715G2852-3-4 ODM MODEL 2.POWER G2852-3-4-X-6-090818 + C918 680uF/25V IC901 LD7575A PS RT 1 COMP 2 CS 3 GND 4 OUT 5 VCC 6 NC 7 HV 8 D906 FCH10U10 1 2 3 + C922 470PF50V C904 0.22UF - + BD901 KBP208G 2 1 3 4 F901 FUSE 25 D817 LL4148 R829 22R 1/8W R822 1K 1/8W C821 0.1uF/25V R837 47K 1/8W D812 LL4148 R831 1K 1/8W R802 8.2K 1/10W 1% R830 NC +12V C822 1uF/25V R832 10K 1/10W 1% Q805 PDTC144WK C820 220pF50V R808 10K 1/10W 1% R820 10K 1/10W 1% C819 0.0022uF R817 10K 1/10W 1% D805 LL4148 D801 BAV99 3 1 2 R851 6K8 1/10W + C802 470PF50V IC801 TL494IDR 1IN+ 1 1IN- 2 FEEDBACK 3 DTC 4 CT 5 RT 6 GND 7 C1 8 E1 9 E2 10 C2 11 VCC 12 OUTPUT CTRL 13 REF 14 2IN- 15 2IN+ 16 R828 10K 1/10W 1% D802 BAV99 3 1 2 C823 0.0022uF D807 LL4148 Q809 RK7002 D806 LL4148 D811 NC R803 680K 1/10W R839 22R 1/8W R850 22R 1/8W Q811 PMBS3904 Q812 PMBS3906 1 2 3 Q807 N.C R804 100R 1/8W R810 51K OHM 1% 1/8W R863 10K 1/10W 1% C803 30pF/3KV R823 0R05 1/10W 5% R826 1K 1/8W D810 NC R807 10K 1/10W 1% DIM ON/OFF R835 1M 1/10W 5% CN801 CONN 1 2 C842 0.01uF C834 0.1uF/25V R827 1K 1/10W 1% F801 0 OHM 1/4W R824 1K 1/10W 1% Q802 AM9945N-T1-PF S 1 G 2 S 3 G 4 D 8 D 7 D 6 D 5 R818 1K 1/10W 1% Q808 PDTA144WK R862 1M 1/10W 5% R825 22R 1/8W C817 NC D814 LL4148 C838 1500PF/50V C807 0.1uF/25V C846 NC R865 NC R864 NC C835 NC Q801 PMBS3904 Q806 PMBS3904 新增 穝糤 CN802 CONN 1 2 R853 68K 1/10W R814 1K5 1/10W 1% Q804 PMBS3906 1 2 3 C825 0.1uF/25V C839 1500PF/50V C801 30pF/3KV R801 1K5 1/10W 1% R854 NC F19S R841 68K OHM 1% 1/10W R861 NC C845 2.2uF/16V R821 1K 1/8W OEM MODEL Size Rev Date Sheet of TPV MODEL PCB NAME 称爹 T P V ( Top Victory Electronics Co . , Ltd. ) Key Component 絬 隔 瓜 絪 腹 PWPC9821GHD1 A Custom 3 4 Tuesday , August 18, 2009 715G2852-3-4 ODM MODEL 3.INVERTER G2852-3-4-X-6-090818 C824 0.1uF R856 15R 1/4W T801 POWER X'FMR 6 3 7 4 8 1 R855 15R 1/4W 26 7.料件清单 注意: 以下料件信息仅供参考，如有变更，恕不另行通知，请到 http://cs.tpv.com.cn 获取最新信息。 T89GHDNDW5A3NNE 点位 组件 对象描述 备注 026G 800504 H BARCODE 040G 58162435A P/N LABEL FOR MANUAL PE BAG 052G 1150 C INSULATING TAPE 052G 1186 SMALL TAPE 052G 1207 A Conductive Tape 45mm *25mm *0.08mm (单导） 052G 1211 B Conductive Tape 85mm *40mm *0.09mm (单导) 052G6019 1 INSULATING TAPE E08902 089G 715HAAE01 SIGNAL CABLE E08901 089G414A15N HL POWER CORD 1.5M E09502 095G8014 6TE01 HARNESS 6P-6P 160MM 095G8018 3XH55 HARNESS 30P-30P 140MM 0D1G1730 8120 SCREW 0M1G1740 12120 SCREW 42-D021241 705GH934056 18.5 STAND ASS'Y E750 750GLG185W1C14N000 PANEL LM185WH1-TLC1 WH LGD H15G0023501 MAIN FRAME H40G 18N61535B 931Sn PRC ID LABEL H40G 58169017A CEL-1 LABEL H40G 58261511B CARTON LABEL H40G 58261546A BASIC SILVE LABEL H41G7800615 7F WARRANTY BOOKLIST H41G780061592A 931SwI QSG BLACK H44G9903615 2C 931Sn CARTON H45G 77 6 PE PACKING H45G 87 1 4H A EPE COVER H70G200961522C CD MANUAL J44G9903101 EPS CUSHION J44G9903201 EPS CUSHION KEPC9HAC KEY BAORD PWPC9821GHD1 POWER BAORD Q33G0188AED 1L0100 key pad Q33G0189 1 1C0100 LENS Q34G0358BBM 1B0100 LOGO LOOP Q34G0452AEDD2B0130 Bezel Q34G0453ABJA4B0100 REAR COVER18.5" 27 Q34G0455AED 1B0100 STAND COVER Q45G 76 28 H A PE BAG FOR MANUAL Q50G 4 10 TIE (Y1900221) Q52G 1185 99 big carton tape for aoc 0Q1G1030 8120 SCREW Q01G6022 2 SCREW Q34G0360AED 1B0130 BASE Q34G0454AED 1B0100 STAND Q37G0101011 HINGE(AOC 831Sw) 756GH9CB A4028 MAIN BOARD-CBPC9HDA1HA U402 056G1133 81 SST25LF020A-33-4C-SAE SMTCR-U402 100GAHG8005W11 MCU ASS'Y056G1133 81 CN408 033G3802 6B Y W WAFER CN404 033G3802 9B Y W WAFER CN403 033G8027 30 H WAFER 30P 2.0MM RIGHT ANGLE 040G 45762412B CBPC LABEL R438 061G152M33964L RST MOFR 3.3 OHM +-5% 2WS CN101 088G 35315F XH D-SUB 15PIN VERTICAL CONN WITH SCREW X401 093G 2258B J NXS24.576AC20F-KAB11 CN001 033G3802 6H L CONNECTOR 6PIN SW005 077G 602 1A CJ TACT SWITCH SW004 077G 602 1A CJ TACT SWITCH SW003 077G 602 1A CJ TACT SWITCH SW002 077G 602 1A CJ TACT SWITCH SW001 077G 602 1A CJ TACT SWITCH LED001 081G 122CT GH Φ3 黄蓝双色弯脚型 LED CN802 033G8021 2E F WAFER CN801 033G8021 2E F WAFER 040G 45762412B CBPC LABEL IC902 056G 139 3A IC PC123Y22FZ0F NR901 061G 58080 WT 8 OHM NCT C908 063G107K224 UM X2 CAP 0.22uF K 275VAC C904 063G107K224 UM X2 CAP 0.22uF K 275VAC C801 065G 3J3006ET 30PF 5% SL 3KV TDK C803 065G 3J3006ET 30PF 5% SL 3KV TDK C901 065G305M1022BP Y2 1000PF M 250VAC Y5P C902 065G305M1022BP Y2 1000PF M 250VAC Y5P C900 065G306M3322BP 3300PF 20% C907 067G 40Z82015K EC 82uF M 450V 18*35mm C802 067G215D4714KV E.C 105℃ CAP 470UF M 25V ED SERIES 28 C940 067G215P1023XV CAP 105℃ 1000UF M 16V C922 067G215P4714AV CAP 105℃ 470UF M 25V C918 067G215P6814XV CAP 105C 680UF M 25V C917 067G215P6814XV CAP 105C 680UF M 25V C915 067G215S4713KV EC 105℃ CAP 470UF M 16V L904 073G 253 91 V1 CHOKE COIL 1.1uH L903 073G 253 91 V1 CHOKE COIL 1.1uH L901 073L 174 40 HG GBQM4.778.391 CN901 087G 501 32 S AC SOCKET D905 093G 60519 DIODE SR560 5A/60V DO-27 SECOS CN902 095G 82510TE12 HARNESS 10P-9P 120MM 705GQ857020 Q901 ASS'Y 705GQ893028 D906 ASS'Y PW9821MHD3SMT POWER BOARD FOR SMT T801 S80GL17T40V Transformer T901 S80GL19T26V Transformer ASS'Y R908 061G152M10452T RST MOFR 100KOHM +-5% 2WS BD901 093G 50460 28 BRIDGE DIODE KBP208G LITEON C424 067G 3051013PB EC 105℃ 100uF M 16V 5*11mm C427 067G 3051013PB EC 105℃ 100uF M 16V 5*11mm C426 067G 3051013PB EC 105℃ 100uF M 16V 5*11mm C423 067G 3051013PB EC 105℃ 100uF M 16V 5*11mm C421 067G 3151014KB EC 100uF M 25V 6.3*11 U405 056G 56327A IC AP1117E18LA SOT223-3L ANACHIP U404 056G 563514 IC AZ1117H-3.3TRG1 1A/3.3V SOT223 U102 056G 662 13 IC AZC099-04S SOT23-6L U103 056G 662 13 IC AZC099-04S SOT23-6L U401 056G1126 48 IC HX6803-A000LAG LQFP-64 U406 056G1133 32 IC M24C04-WMN6TP SO8 U101 056G1133 34 M24C02-WMN6TP U402 056G1133 81 SST25LF020A-33-4C-SAE Q401 057G 417 6 PMBS3906/PHILIPS-SMT(06) Q402 057G 417 6 PMBS3906/PHILIPS-SMT(06) Q404 057G 417 6 PMBS3906/PHILIPS-SMT(06) Q412 057G 417 12 T KEC 2N3904S-RTK/PS Q411 057G 417 12 T KEC 2N3904S-RTK/PS Q410 057G 417 12 T KEC 2N3904S-RTK/PS Q406 057G 417 12 T KEC 2N3904S-RTK/PS Q405 057G 763 1 A03401 SOT23 BY AOS(A1) R466 061G0402000 RST CHIP MAX 0R05 1/16W 29 R469 061G0402000 RST CHIP MAX 0R05 1/16W R476 061G0402000 RST CHIP MAX 0R05 1/16W R473 061G0402101 RST CHIPR 100 OHM +-5% 1/16W R472 061G0402101 RST CHIPR 100 OHM +-5% 1/16W R471 061G0402101 RST CHIPR 100 OHM +-5% 1/16W R420 061G0402101 RST CHIPR 100 OHM +-5% 1/16W R412 061G0402101 RST CHIPR 100 OHM +-5% 1/16W R411 061G0402101 RST CHIPR 100 OHM +-5% 1/16W R113 061G0402101 RST CHIPR 100 OHM +-5% 1/16W R110 061G0402101 RST CHIPR 100 OHM +-5% 1/16W R441 061G0402102 RST CHIPR 1 KOHM +-5% 1/16W R103 061G0402102 RST CHIPR 1 KOHM +-5% 1/16W R102 061G0402102 RST CHIPR 1 KOHM +-5% 1/16W R456 061G0402102 RST CHIPR 1 KOHM +-5% 1/16W R455 061G0402102 RST CHIPR 1 KOHM +-5% 1/16W R453 061G0402102 RST CHIPR 1 KOHM +-5% 1/16W R118 061G0402102 RST CHIPR 1 KOHM +-5% 1/16W R488 061G0402103 RST CHIPR 10 KOHM +-5% 1/16W R487 061G0402103 RST CHIPR 10 KOHM +-5% 1/16W R482 061G0402103 RST CHIPR 10 KOHM +-5% 1/16W R475 061G0402103 RST CHIPR 10 KOHM +-5% 1/16W R467 061G0402103 RST CHIPR 10 KOHM +-5% 1/16W R462 061G0402103 RST CHIPR 10 KOHM +-5% 1/16W R461 061G0402103 RST CHIPR 10 KOHM +-5% 1/16W R460 061G0402103 RST CHIPR 10 KOHM +-5% 1/16W R457 061G0402103 RST CHIPR 10 KOHM +-5% 1/16W R439 061G0402103 RST CHIPR 10 KOHM +-5% 1/16W R437 061G0402103 RST CHIPR 10 KOHM +-5% 1/16W R433 061G0402103 RST CHIPR 10 KOHM +-5% 1/16W R421 061G0402103 RST CHIPR 10 KOHM +-5% 1/16W R407 061G0402103 RST CHIPR 10 KOHM +-5% 1/16W R404 061G0402103 RST CHIPR 10 KOHM +-5% 1/16W R121 061G0402103 RST CHIPR 10 KOHM +-5% 1/16W R120 061G0402103 RST CHIPR 10 KOHM +-5% 1/16W R401 061G0402105 RST CHIPR 1MOHM +-5% 1/16W R410 061G0402121 RST CHIP 120R 1/16W 5% R414 061G0402121 RST CHIP 120R 1/16W 5% R402 061G0402162 RST CHIP 1K6 1/16W 5% R105 061G0402222 RST CHIPR 2.2 KOHM +-5% 1/16W R106 061G0402222 RST CHIPR 2.2 KOHM +-5% 1/16W 30 R109 061G0402390 0F RST CHIP 390R 1/16W 1% R104 061G0402391 JF RST CHIP 390R 1/16W 5% FENGHUA R111 061G0402391 JF RST CHIP 390R 1/16W 5% FENGHUA R115 061G0402391 JF RST CHIP 390R 1/16W 5% FENGHUA R427 061G0402392 RST CHIP 3.9K 1/16W 5% R428 061G0402392 RST CHIP 3.9K 1/16W 5% R477 061G0402472 RST CHIPR 4.7 KOHM +-5% 1/16W R440 061G0402472 RST CHIPR 4.7 KOHM +-5% 1/16W R435 061G0402472 RST CHIPR 4.7 KOHM +-5% 1/16W R416 061G0402472 RST CHIPR 4.7 KOHM +-5% 1/16W R415 061G0402472 RST CHIPR 4.7 KOHM +-5% 1/16W R125 061G0402472 RST CHIPR 4.7 KOHM +-5% 1/16W R119 061G0402472 RST CHIPR 4.7 KOHM +-5% 1/16W R481 061G0402473 RST CHIPR 47 KOHM +-5% 1/16W R450 061G0402512 RST CHIP 5K1 1/16W 5% R436 061G0402513 RST CHIP 51K 1/16W 5% R465 061G0402682 RST CHIP 6K8 1/16W 5% R107 061G0402750 RST CHIPR 75 OHM +-5% 1/16W R112 061G0402750 RST CHIPR 75 OHM +-5% 1/16W R116 061G0402750 RST CHIPR 75 OHM +-5% 1/16W R434 061G1206331 RST CHIPR 330 OHM +-5% 1/4W C121 065G0402100 31 CAP 0402 10PF J 50V NPO C122 065G0402100 31 CAP 0402 10PF J 50V NPO C120 065G0402100 31 CAP 0402 10PF J 50V NPO C405 065G0402103 32 0.01uF +-10% 16V X7R C419 065G040210412K A CAP CHIP 0402 100nF K 16V X7R C420 065G040210412K A CAP CHIP 0402 100nF K 16V X7R C422 065G040210412K A CAP CHIP 0402 100nF K 16V X7R C428 065G040210412K A CAP CHIP 0402 100nF K 16V X7R C431 065G040210412K A CAP CHIP 0402 100nF K 16V X7R C432 065G040210412K A CAP CHIP 0402 100nF K 16V X7R C433 065G040210412K A CAP CHIP 0402 100nF K 16V X7R C436 065G040210412K A CAP CHIP 0402 100nF K 16V X7R C437 065G040210412K A CAP CHIP 0402 100nF K 16V X7R C438 065G040210412K A CAP CHIP 0402 100nF K 16V X7R C439 065G040210412K A CAP CHIP 0402 100nF K 16V X7R C450 065G040210412K A CAP CHIP 0402 100nF K 16V X7R C118 065G040210412K A CAP CHIP 0402 100nF K 16V X7R C401 065G040210412K A CAP CHIP 0402 100nF K 16V X7R C403 065G040210412K A CAP CHIP 0402 100nF K 16V X7R 31 C404 065G040210412K A CAP CHIP 0402 100nF K 16V X7R C406 065G040210412K A CAP CHIP 0402 100nF K 16V X7R C407 065G040210412K A CAP CHIP 0402 100nF K 16V X7R C409 065G040210412K A CAP CHIP 0402 100nF K 16V X7R C413 065G040210412K A CAP CHIP 0402 100nF K 16V X7R C414 065G040210412K A CAP CHIP 0402 100nF K 16V X7R C415 065G040210412K A CAP CHIP 0402 100nF K 16V X7R C416 065G040210412K A CAP CHIP 0402 100nF K 16V X7R C417 065G040210412K A CAP CHIP 0402 100nF K 16V X7R C447 065G0402105 A5 CAP 0402 1UF K 10V X5R C103 065G0402220 31 CHIP 22PF 50V NPO C102 065G0402220 31 CHIP 22PF 50V NPO C408 065G0402224 17 CAP CER 0.22UF -20%-80% C444 065G0402224 A5 MLCC 0402 CAP 0.22UF K 10V X5R C411 065G0402330 31 CHIP CAP 0402 33pF J 50V NPO C412 065G0402330 31 CHIP CAP 0402 33pF J 50V NPO C110 065G0402473 12 CHIP 0.047uF 16V X7R C107 065G0402473 12 CHIP 0.047uF 16V X7R C106 065G0402473 12 CHIP 0.047uF 16V X7R C101 065G0402473 12 CHIP 0.047uF 16V X7R C456 065G0805105 22 CAP CHIP 0805 1uF K 25V X7R C455 065G0805106 A7 CHIP 10uF 10V Y5V 0805 C442 065G0805106 A7 CHIP 10uF 10V Y5V 0805 C441 065G0805106 A7 CHIP 10uF 10V Y5V 0805 C402 065G080547515K T CAP CHIP 0805 4.7UF K 16V X5R FB407 071G 56G301 EA BEAD 300 欧 FB402 071G 56K121 M CHIP BEAD FB104 071G 59G301 CHIP BEAD 300OHM R123 071G 59K190 B 19 OHM BEAD R124 071G 59K190 B 19 OHM BEAD R122 071G 59K190 B 19 OHM BEAD FB406 071G 59K190 B 19 OHM BEAD FB405 071G 59K190 B 19 OHM BEAD R101 071G 59K800 CHIP BEAD 80 OHM FCM1608K-800 FB409 071G 59S221 M CHIP BEAD 0603 220ohm+-25% 2A D403 093G 60505 DIO SIG SM BAT54C(PHSE)R D105 093G 64 42 L DIODE LBAV70LT1G SOT-23 LRC ZD103 093G 39S 34 T UDZSNP5.6B ROHM ZD104 093G 39S 34 T UDZSNP5.6B ROHM D402 093G2004 2 DIODE SR24 32 715G2681 1 4 MAIN BOARD PCB R003 061G0603000 RST CHIP MAX 0R05 1/10W R005 061G0603102 RST CHIPR 1K OHM +-5% 1/10W R002 061G0603202 RST CHIPR 2 KOHM +-5% 1/10W R004 061G0603202 RST CHIPR 2 KOHM +-5% 1/10W J001 061G1206000 RST CHIP MAX 0R05 1/4W J002 061G1206000 RST CHIP MAX 0R05 1/4W 715G2991 2 KEY BOARD PCB Q901 057G 667 51 FET 2SK4101LS 7A/650V TO-220FI(LS) 0M1G 930 8120 SCREW HS3 Q90G6263 6 HEAT SINK D906 093G 60267 SP10100 0M1G 930 8120 SCREW HS2 Q90G6263 6 HEAT SINK IC801 056G 379 22 IC TL494IDR SOIC-16 IC901 056G 379107 IC LD7575A PS SOP-8 Q804 057G 417517 Tra LMBT3906LT1G -200mA/-40V SOT-23 LRC Q812 057G 417517 Tra LMBT3906LT1G -200mA/-40V SOT-23 LRC Q801 057G 417518 TRA LMBT3904LT1G 200mA/40V SOT-23 LRC Q806 057G 417518 TRA LMBT3904LT1G 200mA/40V SOT-23 LRC Q807 057G 417518 TRA LMBT3904LT1G 200mA/40V SOT-23 LRC Q811 057G 417518 TRA LMBT3904LT1G 200mA/40V SOT-23 LRC Q903 057G 417518 TRA LMBT3904LT1G 200mA/40V SOT-23 LRC Q809 057G 759 2 RK7002FD5T116 SOT-23 BY ROHM Q808 057G 760 4A DTA144WN3/S SOT-23 Q805 057G 760 5A DTC 144WN3/S SOT-23 Q802 057G 763 6 AO4828 SOIC-8 BY AOS R823 061G0603000 RST CHIP MAX 0R05 1/10W R942 061G0603100 1F RST CHIPR 1 KOHM +-1% 1/10W R926 061G0603100 1F RST CHIPR 1 KOHM +-1% 1/10W R827 061G0603100 1F RST CHIPR 1 KOHM +-1% 1/10W R824 061G0603100 1F RST CHIPR 1 KOHM +-1% 1/10W R818 061G0603100 1F RST CHIPR 1 KOHM +-1% 1/10W R863 061G0603100 2F RST CHIPR 10K OHM +-1% 1/10W R832 061G0603100 2F RST CHIPR 10K OHM +-1% 1/10W R828 061G0603100 2F RST CHIPR 10K OHM +-1% 1/10W R820 061G0603100 2F RST CHIPR 10K OHM +-1% 1/10W R817 061G0603100 2F RST CHIPR 10K OHM +-1% 1/10W R808 061G0603100 2F RST CHIPR 10K OHM +-1% 1/10W R807 061G0603100 2F RST CHIPR 10K OHM +-1% 1/10W 33 R862 061G0603105 RST CHIPR 1M OHM +-5% 1/10W R801 061G0603150 1F RST CHIPR 1.5 KOHM +-1% 1/10W R814 061G0603150 1F RST CHIPR 1.5 KOHM +-1% 1/10W R930 061G0603243 1F RST CHIPR 2.43K OHM +-1% 1/10W R940 061G0603330 2F RST CHIPR 33K OHM +-1% 1/10W R927 061G0603360 1F RST CHIPR 3.6K OHM +-1% 1/10W R861 061G06034753FF RST CHIPR 475KOHM +-1% 1/10W FENGHUA R851 061G0603680 1F RST CHIPR 6.8 KOHM +-1% 1/10W R841 061G0603680 2F RST CHIPR 68K OHM +-1% 1/10W R853 061G0603683 RST CHIPR 68K OHM +-5% 1/10W R854 061G0603683 RST CHIPR 68K OHM +-5% 1/10W R803 061G0603684 RST CHIPR 680 KOHM +-5% 1/10W R802 061G0603820 1F RST CHIPR 8.2 KOHM +-1% 1/10W JR902 061G0805000 RST CHIP MAX 0R05 1/8W R822 061G0805100 1F RST CHIPR 1K OHM +-1% 1/8W R821 061G0805100 1F RST CHIPR 1K OHM +-1% 1/8W R831 061G0805100 1F RST CHIPR 1K OHM +-1% 1/8W R915 061G0805100 3F RST CHIPR 100KOHM +-1% 1/8W R804 061G0805101 1ST CHIPR 100 OHM +-5% 1/8W R939 061G0805102 RST CHIPR 1K OHM +-5% 1/8W R826 061G0805102 RST CHIPR 1K OHM +-5% 1/8W R925 061G0805102 RST CHIPR 1K OHM +-5% 1/8W R938 061G0805103 RST CHIPR 10K OHM +-5% 1/8W R924 061G0805151 RST CHIPR 150 OHM +-5% 1/8W R850 061G0805220 RST CHIPR 22 OHM +-5% 1/8W R839 061G0805220 RST CHIPR 22 OHM +-5% 1/8W R829 061G0805220 RST CHIPR 22 OHM +-5% 1/8W R825 061G0805220 RST CHIPR 22 OHM +-5% 1/8W R943 061G0805471 RST CHIPR 470 OHM +-5% 1/8W R837 061G0805473 RST CHIPR 47K OHM +-5% 1/8W R810 061G0805510 2F RST CHIPR 51K OHM +-1% 1/8W JR801 061G1206000 RST CHIP MAX 0R05 1/4W F801 061G1206000 4 RST CHIP MAX 0R05 1/4W F905 061G1206000 4 RST CHIP MAX 0R05 1/4W R910 061G1206100 RST CHIPR 10 OHM +-5% 1/4W R918 061G1206101 RST CHIPR 100 OHM +-5% 1/4W R919 061G1206101 RST CHIPR 100 OHM +-5% 1/4W R920 061G1206101 RST CHIPR 100 OHM +-5% 1/4W R935 061G1206101 RST CHIPR 100 OHM +-5% 1/4W R961 061G1206101 RST CHIPR 100 OHM +-5% 1/4W 34 R962 061G1206101 RST CHIPR 100 OHM +-5% 1/4W R904 061G1206103 RST CHIPR 10K OHM +-5% 1/4W R932 061G1206103 RST CHIPR 10K OHM +-5% 1/4W R856 061G1206150 RST CHIPR 15 OHM +-5% 1/4W R855 061G1206150 RST CHIPR 15 OHM +-5% 1/4W R912 061G1206221 RST CHIPR 220 OHM +-5% 1/4W R909 061G1206519 RST CHIPR 5.1 OHM +-5% 1/4W R900 061G1206684 RST CHIPR 680K OHM +-5% 1/4W R901 061G1206684 RST CHIPR 680K OHM +-5% 1/4W R902 061G1206684 RST CHIPR 680K OHM +-5% 1/4W C932 065G0603102 32 1000PF +-10% 50V X7R C842 065G0603103 32 CAP CHIP 0603 0.01UF K 50V X7R C834 065G0603103 32 CAP CHIP 0603 0.01UF K 50V X7R C825 065G0603104 22 CAP CHIP 0603 0.1UF K 25V X7R C821 065G0603104 22 CAP CHIP 0603 0.1UF K 25V X7R C807 065G0603104 22 CAP CHIP 0603 0.1UF K 25V X7R C823 065G0603222 32 CHIP 2200PF 50V X7R C819 065G0603222 32 CHIP 2200PF 50V X7R C928 065G0805103 32 CAP CHIP 0805 10NF K 50V X7R C824 065G0805104 32 CAP CHIP 0805 0.1uF K 50V X7R C911 065G0805104 32 CAP CHIP 0805 0.1uF K 50V X7R C924 065G0805104 32 CAP CHIP 0805 0.1uF K 50V X7R C930 065G0805104 32 CAP CHIP 0805 0.1uF K 50V X7R C931 065G0805104 32 CAP CHIP 0805 0.1uF K 50V X7R C822 065G080510522K 3 CAP CHIP 0805 1U 25V X7R +/-10% C838 065G0805152 31 1.5nF/50V C839 065G0805152 31 1.5nF/50V C820 065G080522131G CAP CHIP 0805 220PF G 50V NPO C845 065G080522512K 3 CAP CHIP 0805 2U2 16V X7R +/-10% C909 065G0805471 31 CHIP 470PF 50V NPO C929 065G1206102 72 CAP CHIP 1206 1000PF K 500V X7R C912 065G1206102 72 CAP CHIP 1206 1000PF K 500V X7R D802 093G 6433L DIODE LBAV99LT1G SOT-23 LRC D801 093G 6433L DIODE LBAV99LT1G SOT-23 LRC ZD922 093G 39GA26 T ZENER DIODE RLZ5.1B SEMTECH ZD921 093G 39GA28 T ZENER DIODE RLZ13B SEMTECH ZD902 093G 39GA28 T ZENER DIODE RLZ13B SEMTECH ZD905 093G 39GA31 T ZENER DIODE RLZ18B SEMTECH D812 093G 64S522SEM LL4148 D805 093G 64S522SEM LL4148 35 D806 093G 64S522SEM LL4148 D807 093G 64S522SEM LL4148 D916 093G 64S522SEM LL4148 D814 093G 64S522SEM LL4148 D817 093G 64S522SEM LL4148 D903 093G 64S522SEM LL4148 D915 093G 64S522SEM LL4148 709G2852 HS001 CONSUMPTIVE ASS'Y PW8521VYD2AI POWER BOARD FOR AI 052G 2191 A PAPER TAPE CN901 006G 31500 EYELET IC903 056G 158 10 T IC AS431AZTR-E1 TO-92 R946 061G152M15152T RST MOFR 150 OHM +-5% 2WS R914 061G152M47852T RST MOFR 0.47 OHM +-5% 2WS C906 065G 2K152 2T6921 CAP CER 1500pF K 2KV Y5P C903 067G 2152207NT KY50VB22M-TP5 5*11 F901 084G 56 3 B FUSE 3.15A 250V D900 093G 6026T52T RECTIFIER DIODE FR107 D901 093G 6038T52T FR103 J903 095G 90 23 C JUMP WIRE J901 095G 90 23 C JUMP WIRE J813 095G 90 23 C JUMP WIRE J812 095G 90 23 C JUMP WIRE J811 095G 90 23 C JUMP WIRE J809 095G 90 23 C JUMP WIRE J807 095G 90 23 C JUMP WIRE J806 095G 90 23 C JUMP WIRE J805 095G 90 23 C JUMP WIRE J904 095G 90 23 C JUMP WIRE J906 095G 90 23 C JUMP WIRE J907 095G 90 23 C JUMP WIRE J908 095G 90 23 C JUMP WIRE J909 095G 90 23 C JUMP WIRE J910 095G 90 23 C JUMP WIRE J911 095G 90 23 C JUMP WIRE J912 095G 90 23 C JUMP WIRE J914 095G 90 23 C JUMP WIRE J804 095G 90 23 C JUMP WIRE J803 095G 90 23 C JUMP WIRE J802 095G 90 23 C JUMP WIRE 36 J801 095G 90 23 C JUMP WIRE 709G2852 HA001 CONSUMPTIVE ASS'Y 715G2852 3 4 POWER BOARD PCB 095G 90 23 JUMPER WIRE
