1 ENGLISH USER'S MANUAL Thank you very much for purchasing the HITACHI Plasma Display Monitor. Before using your monitor, please carefully read the "SAFETY INSTRUCTIONS" and this "USER'S MANUAL" so you will know how to operate the monitor properly. Keep this manual in a safe place. You will find it useful in the future. Notes on lnstallation Work: This product is marketed assuming that it is installed by qualifed personnel with enough skill and competence. Always have an installation specialist or your dealer install and set up the product. HITACHI cannot assume liabilities for damage caused by mistake in installation or mounting, misuse, modification or a natural disaster. Note for Dealers: After installation, be sure to deliver this manual to the customer and explain to the customer how to handle the product. 42PD4200 Downloaded from www.Manualslib.com manuals search engine 2 Important Please read this User's Manual thoroughly, especially the Safety Instructions on Page 4 to 7. Mis-use may cause damage to your plasma monitor, which could shorten its lifespan, or cause injury to yourself. Should you encounter any difficulty in the set-up or operation of your monitor, firstly refer to the Troubleshooting guide at the rear of this manual. In the unlikely event of a problem occurring with your plasma monitor, switch off at the mains sockets, pull out the plugs, and contact your dealer immediately. CAUTION Under no circumstances remove the rear cover of your plasma monitor. Never guess or take any chances with electrical equipment of any kind - it is better to be safe than sorry! Software Notice It is prohibited for the end user of this product to copy, reverse engineer or reverse compile the software included therein, save to the extent permitted by law. Plasma Monitor After the plasma monitor has been on for any length of time, you will notice that the screen becomes warm. Please note that this is normal. Sometimes the screen might have some tiny bright or dark spots. Please note that this is normal. CAUTION To prevent scratches or damages to the plasma screen, do not knock or rub the surface with sharp or hard objects. Clean the screen with a soft cloth moistened with warm water and dry with a soft cloth. A mild soap may be used if the screen is extremely dirty. Do not use harsh or abrasive cleaners! CAUTION Use a soft cloth to clean the cabinet and control panel of the monitor. When excessively soiled dilute a neutral detergent in water, wet and wring out the soft cloth and afterward wipe with a dry soft cloth. Never use acid/alkaline detergent, alcoholic detergent, abrasive cleaner, powder soap, OA cleaner, car wax, glass cleaner, etc. especially because they would cause discoloration, scratches or cracks. Extended definition plasma display panel The 42-inch colour plasma display panel, with a resolution of 852(H) x 480(V) pixels, creates a high-definition, large-screen (aspect ratio : 16:9) and low-profile flat display. Free from electromagnetic interferences from geomagnetic sources and ambient power lines, the panel produces high-quality display images free from colour misconvergence and display distortion. High Performance Digital Processor A wide range of personal computer signals can be handled, from 640 x 400, 640 x 480 VGA to 1600 x 1200 UXGA. (RGB Analog input) Easy-to-use remote control and on screen display system The remote control included eases the work of setting display controls. Further, the on-screen display system, displays the status of signal reception and display control settings in an easy-to-view fashion. Power saving system The International ENERGY STAR® power saver feature saves power consumption automatically when input signals are not available. When connected to a VESA DPMS-compliant PC, the monitor cuts its power consumption while it is idle. TruBass TruBass, SRS and (O) symbol are trademarks of SRS Labs,Inc. TruBass technology is incorporated under license from SRS Labs, Inc. About the Optional Video Unit The following functions can be obtained by connecting the optional video unit. (1) A composite/S terminal and two component terminals have been added. A composite video output terminal is also provided as a monitoring output. (2) A wide range of devices other than personal computers can also be connected. (3) A component input is possible to switch to RGB signals from the Menu screen. (4) A SCART terminal is also provided for the signal of the European standard. It operates as composite/S/RGB input terminal, or video output terminal. Options Ask your local retail dealer for further details. 1. Desktop stand: • CMPAD23 (for 32”) • CMPAD25 (for 42”) 2. Plasma monitor speaker: • CMPAS03 (for 32”) bass reflex speaker unit with 16x4.5cm cone type speaker (colour: dark gray) • CMPAS03S (for 32”) same type to CMPAS03 (colour: light gray) • CMPAS14 (for 42”) 2 way speaker unit with one 2.5cm dome type tweeter and two 8cm round type woofers (colour: dark gray) • CMPAS14S (for 42”) same type to CMPAS14 (colour: light gray) 3. Video unit: CMPAVW1 An expansion unit for viewing video with this device. FEATURES Downloaded from www.Manualslib.com manuals search engine 3 ENGLISH CONTENTS FEATURES ....................................................2 SAFETY INSTRUCTIONS ..............................4 COMPONENT NAMES ..................................8 Main Unit..............................................................................8 Remote control ....................................................................9 Loading Batteries ..............................................................9 Handling the Remote Control ............................................9 INSTALLATION INSTRUCTIONS ................11 Installation..........................................................................11 Anti-tumble measures........................................................11 Connecting to a PC ..........................................................12 Mounting the Speaker Unit ..............................................13 Power Cord Connection ....................................................13 OPERATING INSTRUCTIONS ....................14 Turning Power On and Off ................................................14 Input Switching ..................................................................15 Volume Adjustment............................................................15 Audio Mute ........................................................................15 Size Switching ..................................................................16 Input Signal Screen Display ..............................................16 Using the Menu Screen ....................................................17 PICTURE MENU ................................................................18 AUDIO MENU ....................................................................19 TIMER MENU ....................................................................19 FUNCTION MENU ............................................................20 SETUP MENU ....................................................................21 LANGUAGE MENU............................................................22 Notes about This Manual • The information in this manual is subject to change without notice. • While meticulous care has been taken in the preparation of this manual, you are requested to notify your dealer or us should you have any comments, views or questions about our product. • Fully understand the prerequisites to using the product, such as hardware and software specifications and constraints, in using the product. We are not held liable for damages caused by improper handling of the product. • Reproduction of this manual in whole or in part without our prior written permission is prohibited. • The product names mentioned in this manual may be trademarks or registered trademarks of their respective owners. OTHER FEATURES ....................................22 Automatic Store ................................................................22 Signal Check ....................................................................23 Power Save Mode..............................................................23 IMAGE RETENTION OF PLASMA DISPLAY ......24 NOTES ........................................................24 TROUBLESHOOTING..................................25 Symptoms That Seemingly Appear to be Failures ............25 Actions to Correct Abnormal Displays ..............................27 Video Unit Function ..........................................................28 Tuner Unit Function ..........................................................38 PRODUCT SPECIFICATIONS ......................49 Signal Input........................................................................50 Recommended Signal List ................................................51 Downloaded from www.Manualslib.com manuals search engine 4 SAFETY INSTRUCTIONS This Plasma monitor has been designed and manufactured to meet international safety standards, but like any electrical equipment, care must be taken if you are to obtain the best results and safety is to be assured. Before using this product, please read and understand the Safety Instructions thoroughly to ensure correct usage, and follow all the instructions. This symbol indicates information that, if ignored, could possibly result in personal injury or even death due to incorrect handling. This symbol indicates information that, if ignored, could result possibly in personal injury or physical damage due to incorrect handling. CAUTION Typical Symbols WARNING Various symbols are used in this manual, the user’s manual and on the product itself to ensure correct usage, to prevent danger to the user and others, and to prevent property damage. The meanings of these symbols are described below. It is important that you read these descriptions thoroughly and fully understand the contents. About the Symbols This symbol indicates an additional warning (including cautions). An illustration is provided to clarify the contents. This symbol indicates a prohibited action. The contents will be clearly indicated in an illustration or nearby (the symbol to the left indicates that disassembly is prohibited). This symbol indicates a compulsory action. The contents will be clearly indicated in an illustration or nearby (the symbol to the left indicates that the power plug should be disconnected from the power outlet). Never use the monitor if a problem should occur. Abnormal operations such as smoke, strange odor, no image, no sound, excessive sound, damaged casing, elements, cables, penetration of liquids or foreign matter, etc. can cause a fire or electrical shock. In such case, immediately turn off the power switch and then disconnect the power plug from the power outlet. After making sure that the smoke or odor has stopped, contact your dealer. Never attempt to make repairs yourself because this could be dangerous. Do not insert liquids or foreign objects. Penetration of liquids or foreign objects could result in fire or electrical shock. Use special caution in households where children are present. If liquids or foreign objects should enter the projector, immediately turn off the power switch, disconnect the power plug from the power outlet and contact your dealer. • Do not place the monitor in a bathroom. • Do not expose the monitor to rain or moisture. • Do not place flower vases, pots, cups, cosmetics, liquids such as water, etc on or around the monitor. • Do not place metals, combustibles, etc on or around the monitor. Never disassemble or modify the monitor. The monitor contains high voltage components. Modification could result in fire or electrical shock. • Never remove any fixed cover. Do not give the monitor any shock or impact. If the monitor should be shocked and/or broken, it could result in an injury, and continued use could result in fire or electrical shock. If the glass panel is broken or damaged, immediately turn off the power switch, disconnect the power plug from the power outlet and contact your dealer. Do not place the monitor on an unstable surface. If the monitor should be dropped and/or broken, it could result in an injury, and continued use could result in fire or electrical shock. • Do not place the monitor on an unstable, slant or vibrant surface such as a wobbly or inclined stand. Do not obstruct the ventilation of the monitor. If the ventilation is obstructed during the operation of the monitor or just after switching off the power, it could result in damage and shorten the lifespan of your monitor due to overheating. Make sure there is ample ventilation. • Keep a space of 100mm (10cm) or more between the sides, rear and top of the monitor and other objects such as walls. • Do not place anything around ventilation openings of the monitor. • Never block ventilation openings. • Do not put the plasma screen side up. • Do not cover the monitor with a tablecloth, etc. • Do not place the monitor on a carpet or bedding, or near a curtain. Use only the correct power outlet. Incorrect power supply could result in fire or electrical shock. Use only the correct power outlet depending on the indication on the monitor and the safety standard. • The enclosed power cord must be used depending on the power outlet to be used. WARNING Disconnect the plug from the power outlet. Do not disassemble. Downloaded from www.Manualslib.com manuals search engine 5 ENGLISH • FOR THE CUSTOMERS IN THE U.K. THIS PRODUCT IS SUPPLIED WITH A TWO PIN MAINS PLUG FOR USE IN MAINLAND EUROPE. FOR THE U.K. PLEASE REFER TO THE NOTES ON THIS PAGE. IMPORTANT FOR UNITED KINGDOM WORDING FOR CLASS I EQUIPMENT INSTRUCTION BOOKS AND LABELS The mains lead on this equipment is supplied with a molded plug incorporating a fuse, the value of which is indicated on the pin face of the plug. Should the fuse need to be replaced, an ASTA or BSI approved BS 1362 fuse must be used of the same rating. If the fuse cover is detachable never use the plug with the cover omitted. If a replacement fuse cover is required, ensure it is of the same colour as that visible on the pin face of the plug. Fuse covers are available from your dealer. DO NOT cut off the mains plug from this equipment. If the plug fitted is not suitable for the power points in your home or the cable is too short to reach a power point, then obtain an appropriate safety approved extension lead or consult your dealer. Should it be necessary to change the mains plugs, this must be carried out by a competent person, preferably a qualified electrician. If there is no alternative to cutting off the mains plug, ensure that you dispose of it immediately, having first removed the fuse, to avoid a possible shock hazard by inadvertent connection to the mains supply. WARNING: THIS EQUIPMENT MUST BE EARTHED IMPORTANT The wires in the mains lead are coloured in accordance with the following code : Green and Yellow = Earth, Blue = Neutral, Brown = Live. As these colours may not correspond with the coloured markings identifying the terminals in your plug, proceed as follows: The wire which is coloured GREEN and YELLOW must be connected to the terminal in the plug which is marked with the letter E or by the earth symbol or coloured GREEN or GREEN and YELLOW. The wire coloured BLUE must be connected to the terminal marked with the letter N or coloured BLUE or BLACK. The wire coloured BROWN must be connected to the terminal marked with the letter L or coloured BROWN or RED. Brown to Live Fuse Cord Clamp Green & Yellow to Earth Blue to Neutral Be cautious of the power cord connection. Incorrect connection of the power cord could result in fire or electrical shock. • Do not touch the power cord with a wet hand. • Check that the connecting portion of the power cord is clean (with no dust), before using. Use a soft and dry cloth to clean the power plug. • Insert the power plug into a power outlet firmly. Avoid using a loose, unsound outlet or contact failure. • Do not cut off the fitted power plug, the removal of which could lead to impaired performance. If you wish to extend the lead, obtain an appropriate extension lead or consult your dealer. • Should you require replacing the fuse in the molded plug with a new fuse, then please replace with new one of the same value, type and approval as the original. Ensure the fuse cover is returned to its original position. Be sure to keep safety ground connection. Connect the ground terminal of AC inlet of this monitor with the ground terminal provided at the power outlet using the enclosed power cord. If the provided plug does not fit your outlet, consult an electrician for replacement of the obsolete outlet. Be careful in handling the power cord and external connection cables. If you keep using a damaged the power cord or cables, it can cause a fire or electrical shock. Do not apply too much heat, pressure or tension to the power cord and cables. If the power cord or cables are damaged (exposed or broken core wires, etc.), contact your dealer. • Do not place the monitor or heavy objects on the power cord and cables. Also, do not place a spread, cover, etc, over them because this could result in the inadvertent placing of heavy objects on the concealed power cord or cables. • Do not pull the power cord and cables. When connecting and disconnecting the power cord or cables, do it with your hand holding the plug or connector. • Do not place the cord near the heater. • Do not touch the power plug just after disconnecting it from the power outlet to prevent electric shock. • Do not touch the power plug when lightening is close to you. • Avoid coiling the power cord and bending it sharply. • Protect the power cord from being walked on, pinched particularly at plugs, conveniences receptacles, and the point where they exit from the apparatus. • Do not modify the power cord. Be careful in handling the battery of the remote control. Incorrect handling of the battery could result in fire or personal injury. The battery may explode if not handled properly. • Keep the battery away from children and pets. If swallowed consult a physician immediately for emergency treatment. • Do not allow the battery to be exposed to fire or water. • Avoid fire or high-temperature environment. • Do not hold the battery with metallic tweezers. • Keep the battery in a dark, cool and dry place. • Do not short circuit the battery. • Do not recharge, disassemble or solder the battery. • Do not physically impact the battery. • Use only the battery specified in the manual of this monitor. • Make sure the plus and minus terminals are correctly aligned when loading the battery. • If you observe a leakage of the battery, wipe out the liquid and then replace the battery. If the liquid adheres your body or clothes, rinse well with water. • Obey the local laws on disposing the battery. WARNING Surely connect the ground wire. Downloaded from www.Manualslib.com manuals search engine 6 PRECAUTIONS • Installation environment Do not obstruct a ventilation hole. Do not put the monitor on carpet or blanket, or near a curtain which has a possibility of obstructing a ventilation hole of the monitor. Do not put the monitor in the following places. • Hot places such as near heater, place exposed to the direct rays of the sun. • A place where the temperature is widely changing. • Places with soot, dust or high humidity. • Poor air ventilation place. • Place near fire. • A wet place such as bathroom, or shower room. • Place where you can trip over it. • Always vibrating or strongly vibrating places. • Distorted or unstable places. • How to view the monitor If you use the monitor in too dark a room, your eyes may become tired. Please use it in a reasonably bright room. Avoid direct rays of the sun to the screen in order to prevent eye fatigue. Your eyes will get fatigued after viewing the monitor for long period of time. Relax your eyes by viewing away from the monitor from time to time. Please watch the monitor in downward direction. • Note on image retention The plasma monitor illuminates phosphor to display images. The phosphor has a finite illumination life. After extended periods of illumination, the brightness of the phosphor will be degraded to such extent that stationary images would burn-in that part of the screen as grayed-out images. Tips to prevent such image retention are: - Do not display images having sharp brightness differences or high-contrast images, such as monochrome characters and graphic patterns, for long. - Do not leave stationary images appearing for long, but try to refresh them at appropriate intervals of time, or try to move them using screen saver function. - Turn down the contrast and brightness controls. • How to clean the plasma screen panel of the monitor Before cleaning the monitor, turn off the monitor and disconnect the power plug from the power outlet. To prevent scratching or damaging the plasma screen face, do not knock or rub the surface with sharp or hard objects. Clean the screen with a soft cloth moistened with warm water and dry with a soft cloth. If it is not enough, then use a cloth with mild detergent. Do not use harsh or abrasive cleaners. • How to clean the cabinet of the monitor Use a soft cloth to clean the cabinet and control panel of the monitor. When excessively soiled dilute a neutral detergent in water, wet and wring out the soft cloth and afterward wipe with a dry soft cloth. Never use acid/alkaline detergent, alcoholic detergent, abrasive cleaner, powder soap, OA cleaner, car wax, glass cleaner, etc. especially because they would cause discoloration, scratches or cracks. CAUTION Be careful in moving the monitor. Neglect could result in an injury or damage. • Do not move the monitor during use. Before moving, disconnect the power plug and all external connections. • You are advised to move the monitor with two persons. • Avoid any impact or shock to the monitor; particularly take care of glass screen. Do not put anything on top of the monitor. Placing anything on the monitor could result in loss of balance or falling, and cause an injury or damage. Use special caution in households where children are present. Avoid a humid or dusty place. Placing the monitor in a smoke, a highly humid, dusty place, oily soot or corrosive gas could result in fire or electrical shock. • Do not place near the kitchen, a humidifier or other place where there is oil, smoke or humidity. Avoid a high temperature environment. The heat could have adverse influence on the monitor and other parts, and could result in transformation, melting or fire. • Do not place the monitor, the remote control and other parts in direct sunlight or near a hot object such as heater, etc. • Do not put the monitor in a place where the temperature is widely changing. Remove the power cord for complete separation. • For safety purposes, disconnect the power cord if the monitor is not to be used for prolonged periods of time. • Before cleaning, turn off and unplug the monitor. Neglect could result in fire or electrical shock. SAFETY INSTRUCTIONS(continued) Disconnect the plug from the power outlet. Downloaded from www.Manualslib.com manuals search engine 7 ENGLISH • Prevention of an obstacle to Radio receivers This monitor has been designed pursuant to the international EMI standards. This is to prevent a problem to Radio receivers. - Keep the monitor away from Radio. - Adjust Radio antennas in order for the monitor not to receive interference. - The antenna cable of Radio should be kept away from the monitor. - Use a coaxial cable for antenna. You can check if this monitor influences Radio receivers by turning off all other equipment other than the monitor. If you find a problem receiving Radio when using the monitor, check the instructions mentioned above. • Precautions for the cable connection - Do ensure that all connections, (including the power plug, extension leads and interconnections between the pieces of equipment), are properly made and in accordance with the manufacturers instructions. Switch off and withdraw the power plug before making or changing connections. - Confirm the connector is fixed tightly when the signal cable is connected. Also confirm the screws on the connector are tightened. - Plug the power cord of the monitor into a different socket from that for other equipment, such as Radio etc.. - Use a plug with ground terminal and make sure that it connects to the ground. • Precaution during transportation Please pay attention when you transport this monitor because it is heavy. Furthermore, use the original carton box and its packaging materials when the monitor is transported. Failure to transport the monitor in any carton except the original carton may result in damage to the monitor. Save the original carton box and all packing material. Do not physically impact the remote control. A physical impact could cause damage or malfunction of the remote control. • Take care not to drop the remote control. • Do not place heavy objects on the remote control. Avoid strong rays. Any strong rays (such as direct sun rays or room lighting) onto the remote control sensors could invalidate the remote control. Avoid radio interference. Any interfering radiation could cause distorted images or noises. • Avoid radio generator such as a mobile telephone, transceiver, etc. around the monitor. Set the sound volume at a suitable level. It is better to keep the volume level low and close the windows at night to protect the neighborhood environment. • Precautions for the installation - Do not use makeshift stands and NEVER fix legs with wood screws - to ensure complete safety, always fit the manufacturers approved stand or legs with the fixings provided according to the instructions. - Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over. - This product is designed to comply with the recommended safety standards for tilt and stability. Do not apply excessive pulling force to the front, or top, of the cabinet that could cause the product to overturn resulting in product damage and/or personal injury. - Follow instructions for wall, shelf or ceiling mounting as recommended by the manufacturer. - Only use the attachments/accessories specified by the manufacturer. - Consult your dealer if you are in any doubt about installation, operation or safety of your equipment. • Other precautions - Do not leave equipment switched on when it is unattended unless it is specifically stated that it is designed for unattended operation or has a stand-by mode. Switch off using the switch on the equipment and show your family how to do this. Make special arrangements for infirm or handicapped people. - Disposal of this product may require specific instructions pertaining to your resident region. - Never guess or take any chances with electrical equipment of any kind - it is better to be safe than sorry! Downloaded from www.Manualslib.com manuals search engine 8 Caution when moving the main unit • As this product is heavy, whenever it is moved, two people are required to transport it safely. • Whenever the unit is moved it should be lifted forwards using the two handgrips at the back, and the unit should then be held at the base on both sides for stability. COMPONENT NAMES Front Cabinet (front frame) Panel Remote-control receiver 9 PROGRAM DOWN button ( SELECT button) INPUT SELECT button (OK button) 15 PROGRAM UP button ( SELECT button) • Adjustment buttons are located on the bottom. • The back cover is provided with indications to distinguish the adjustment buttons. SUB-POWER button 14 Control panel VOLUME UP/DOWN buttons ( ADJUST buttons) 15 Main power switch 14 14 • The main power switch is located at the back, on the lower surface. Indicating lamp External device connection terminals Rear RGB input terminals 12 External speaker terminals Handgrips Handgrips Handgrips Main Unit External speaker terminals 12 12 MENU button 17 • ( ) indicates the function while the MENU is displayed on the screen. ▼ ▼ Downloaded from www.Manualslib.com manuals search engine 9 ENGLISH Remote ID SET button 16 POWER OFF button 13 POWER ON button 13 POWER ON/OFF button 13 MENU button 16 MUTE button 14 VOLUME UP/DOWN buttons 14 RETURN button 16 RECALL button 15 AUTO button 16 PinP button 34 ID button 16 SELECT/ADJUST buttons 16 OK button 16 Loading Batteries 1. Open the battery cover. • Slide back and remove the battery cover in the direction of the arrow. 2. Load batteries. • Load two Size AA batteries included observing the correct polarities. 3. Close the battery cover. • Replace the battery cover in the direction of the arrow and snap it back into place. Use the remote control within about 5 m from front of the unit’s remote-control sensor and within 30 degrees on both sides. With in 30 degrees About 5m About 3m With in 30 degrees About 3m AV1 AV2 RGB 1 RGB 2 AV3 MUTE VOL VOL AV4 AUTO PinP OK SIZE RECALL MENU ID ID SET • Do not use new and old batteries together. The batteries could explode or leak, resulting in fires, physical injury, or stains. • When loading batteries, observe their correct polarities as marked on the product. If loaded in the wrong direction, the batteries could explode or leak, resulting in fires, physical injury, or stains. CAUTION ATTENTION • Do not drop or impact the remote control. • Do not splash the remote control with water or put it on a wet object to avoid possible failures. • Before leaving the remote control out of use for an extended period of time, remove the batteries from it. • If the remote control begins to lack responsiveness, replace the batteries. • Strong light such as direct sunlight impinging on the photoreceptor of the remote control can cause operational failure. Position this unit to avoid direct contact with such light. Handling the Remote Control SIZE button 15 RGB/VIDEO buttons 14 AV1 AV2 RGB 1 RGB 2 AV3 MUTE VOL VOL AV4 AUTO PinP OK SIZE RECALL MENU ID ID SET COMPONENT NAMES (continued) POWER ON / OFF button PICTURE MODE button SURROUND button Loading Batteries 1. Open the battery cover. • Slide back and remove the battery cover in the direction of the arrow. 2. Load batteries. • Load two Size AA batteries included observing the correct polarities. 3. Close the battery cover. • Replace the battery cover in the direction of the arrow and snap it back into place. Use the remote control within about 5 m from front of the unit’s remote-control sensor and within 30 degrees on both sides. With in 30 degrees About 5m About 3m With in 30 degrees About 3m D / N A / B i + MENU OK FREEZE ZOOM AV1 RGB1 RGB2 AV2 AV3 AV4 2-4-12 I / II P+ P- + - D V D 1 2 3 4 5 6 7 8 0 9 • Do not use new and old batteries together. The batteries could explode or leak, resulting in fires, physical injury, or stains. • When loading batteries, observe their correct polarities as marked on the product. If loaded in the wrong direction, the batteries could explode or leak, resulting in fires, physical injury, or stains. CAUTION ATTENTION • Do not drop or impact the remote control. • Do not splash the remote control with water or put it on a wet object to avoid possible failures. • Before leaving the remote control out of use for an extended period of time, remove the batteries from it. • If the remote control begins to lack responsiveness, replace the batteries. • Strong light such as direct sunlight impinging on the photoreceptor of the remote control can cause operational failure. Position this unit to avoid direct contact with such light. Handling the Remote Control AUDIO MODE button RECALL button INPUT SELECT button CH I / II button MULTI PICTURE (PinP) button Buttons for MULTI PICTURE mode RETURN button MENU button PROGRAM UP / DOWN buttons SELECT / ADJUST buttons ( ) VOLUME UP / DOWN buttons OK button DVD CONTROL buttons MUTE button FREEZE button ZOOM button PROGRAM SELECT buttons PROGRAM UP / DOWN buttons RGB / VIDEO buttons TIME button D / N A / B i + MENU OK FREEZE ZOOM AV1 RGB1 RGB2 AV2 AV3 AV4 2-4-12 I / II P+ P- + - DVD 1 2 3 4 5 6 7 8 0 9 Remote control Downloaded from www.Manualslib.com manuals search engine 10 COMPONENT NAMES (continued) Remote control (continued) Dynamic Natural Movie Music Favourite Speech D / N A / B i + MENU OK FREEZE ZOOM AV1 RGB1 RGB2 AV2 AV3 AV4 2-4-12 I / II P+ P- + - DVD 1 2 3 4 5 6 7 8 0 9 PICTURE MODE You may recall the picture mode by pressing this button. Each time pressed, picture mode is changed in following sequence. INPUT SELECT Press this button to change input mode. RECALL You can see the input mode status on the screen by pressing this button. DVD CONTROL You can use these buttons to operate the selected brand of DVD player. PROGRAM SELECT Press these buttons to select a TV program directly. TIME Pressing this button can indicate the time by On-Screen display when receiving a TV program on the screen including TELETEXT service with the time information. AUDIO MODE You may recall the sound mode by pressing this button. Each time pressed, sound mode is changed in following sequence. MATRIX SURROUND Press this button to set Matrix Surround On or Off. MULTI PICTURE Press this button to change the screen to multi-pictures. Press it again to return to normal picture. CH I/II This button is for A2 / NICAM models only. MULTI MODE In multi-picture mode, pressing this button will change the multi-picture mode. MUTE Press this button to turn off the set sound. When press again or the _ volume up button will restore the sound. FREEZE Press this button to change the picture to freeze mode. Press it again to return to normal picture. ZOOM Press this button can change Picture size. Downloaded from www.Manualslib.com manuals search engine 11 ENGLISH Anti-tumble measures Securing to a wall or pillar Using a commercially available cord, chain and clamp, secure the set to a firm wall or pillar. Securing desktop 1) Using wood screws (two), fasten the set to the clamping screw holes on the rear of the stand as shown. 2) Using commercially available wood screws, secure the set firmly in position. INSTALLATION INSTRUCTIONS Installation • Installation of the wall mount unit and ceiling mount unit can be dangerous, so do not attempt this work yourself. Ask your dealer to provide the name of a qualified installer. • In order to prevent an internal temperature increase, maintain a space of 10cm (4 inches : For a desktop set- up) or more between the sides and other objects such as walls, etc., so that the ventilation holes are not blocked.(✻) CAUTION Have this unit mounted in a stable place. Take measures to prevent it from tumbling down to avoid possible physical injury. CAUTION 10cm (4 inches) or more* Cord or chain Clamp Two places Wood screw Hook Chain cord or chain clamp Wall or Pillar Use one of the special mount units to install this product. A mount of insufficient strength or inadequate design can cause overturning or dropping and result in fire, electrical shock or injury. Please note that our company assumes absolutely no responsibility for personal injuries or property damage caused by use of other mount units or improper installation. WARNING • Refer to the installation instructions concerning mounting of the Desk-top Stand. The instruction manual is included with the Desk-top Stand. The Desk-top Stand has been used for the illustrations in this manual. Monitor Desk-top stand Downloaded from www.Manualslib.com manuals search engine 12 Read SAFETY INSTRUCTIONS ( to ) carefully to ensure maximum safety before proceeding to these steps: • Choose an appropriate site and install the product on a level table where the stand is secure. • Install the monitor to have ready access to a power socket available. • Make sure that the power switch of this device is turned off. 7 4 (1) Make sure that the display signal of the personal computer to be used is compatible with the specifications of this device. • See "Product Specifications" concerning the specifications of this device. (2) Make sure that the power switch of the personal computer is turned off. (3) Connect the signal input terminal (RGB 1 or RGB 2) on the rear panel of this device to the display signal output terminal of the personal computer. • Use a cable that fits the input terminal of this device and the output terminal of the personal computer. • Depending on the type of personal computer being connected, the use of an optional conversion adapter or the adapter provided with the personal computer may be necessary in some cases. For details, refer to the instruction manual of the personal computer or ask the personal computer manufacturer or your local retail dealer. Connecting to a PC Monitor rear panel Power cord Power cable connector Speaker (R) Speaker (L) PC (D-sub) (DVI) To signal output terminal To signal output terminal To audio output terminal 3.5mm Stereo mini jack 49 52 ~ Downloaded from www.Manualslib.com manuals search engine 13 ENGLISH ① Connect the power cord to this device. ➁ Connect the power cord plug to the power outlet. (The type of plug is different from this drawing for some countries.) Connect the power cord, after completing all other connections. ① ➁ INSTALLATION INSTRUCTIONS (continued) Power Cord Connection • Use only the power cord provided. • Do not use a power supply voltage other than that indicated (AC100-240V, 50/60Hz) as this may cause fire or electric shock. CAUTION Mounting the Speaker Unit Refer to the installation instructions concerning mounting of the speaker unit. The instruction manual is included with the Speaker Unit. Speakers Downloaded from www.Manualslib.com manuals search engine 14 OPERATING INSTRUCTIONS Turning Power On and Off • To turn the monitor power ON, press the main power switch on the monitor main unit to ON, and then press the SUB POWER button or the ON/OFF or ON button on the remote control. • To turn the monitor power OFF, press the SUB POWER button or the ON/OFF or OFF button on the remote control, and then press the main power switch on the monitor main unit to OFF. • During normal use, the main power switch is set in the ON position, and the monitor can then be turned ON/OFF using the SUB POWER button or the ON/OFF button on the remote control. Indicating lamp Indicating lamp Power status Operating Off Off When the main power switch is set to OFF. Lights red Off (standby) When the main power switch is ON, and the OFF button on the remote control or the SUB POWER button on the underside of the front of the frame is OFF. Lights green On When the main power switch is ON, and the ON button on the remote control or the SUB POWER button on the underside of the front of the frame is ON. Lights orange Off (Power Save) When the main power switch is ON, and the ON button on the remote control or the SUB POWER button on the underside of the front of the frame is ON. However, the state in POWER SAVE mode When the indicating lamp lights in orange or the message “No Sync. Signal”, “Power Save” or “Invalid Scan Freq.” appears on the screen, there is something unusual about the status of reception. See “Power Save Mode” or “Symptoms That Seemingly Appear to be Failures.” D / N A / B i + MENU OK FREEZE ZOOM AV1 RGB1 RGB2 AV2 AV3 AV4 2-4-12 I / II P+ P- + - DVD 1 2 3 4 5 6 7 8 0 9 POWER ON/OFF button SUB-POWER button Main power switch Indicating lamp ATTENTION • Avoid repeatedly turning the monitor on and off at short time intervals. Failures might result from such operation. • Turn off the main power switch before leaving the monitor out of use for an extended period of time. • If a power failure occurs while the main unit is running, it would be powered on upon recovery from the failure. Turn off the unit main power switch before leaving the main unit. 23 25 Downloaded from www.Manualslib.com manuals search engine 15 ENGLISH D / N A / B i + MENU OK FREEZE ZOOM AV1 RGB1 RGB2 AV2 AV3 AV4 2-4-12 I / II P+ P- + - DVD 1 2 3 4 5 6 7 8 0 9 OPERATING INSTRUCTIONS (continued) Audio Mute The audio volume can be temporarily mute by pressing the MUTE button of the remote control. • When a button is pressed, the volume adjustment status guide (magenta) will be displayed. • The volume setting can be lowered by pressing the VOL- button while the audio is mute. • The muting can be cancelled by pressing the VOL+ button or MUTE button while the audio is mute. When the MUTE button of the remote control is pressed again, the audio will be restored and the volume display (green) will appear. MUTE button Input Switching • When a button is pressed, the volume adjustment status guide will be displayed. • The volume will increase when the VOL+ (or ▲) button is pressed while the guide is being displayed. • The volume will decrease when the VOL- (or ▼) button is pressed while the guide is being displayed. Volume Adjustment The volume can be adjusted by pressing the VOL+ and VOL- buttons of the remote control (or the ▲ and ▼ volume buttons of the monitor unit). Volume 15 Volume setting value Adjustment status guide display VOLUME UP/DOWN buttons INPUT SELECT button RGB buttons Adjustment status guide display (The display colour will change to magenta.) VOLUME UP/DOWN buttons Volume 15 Volume setting value ▼ ▼ • Input can be switched by pressing the AV1, AV2, AV3, AV4, RGB1 or RGB2 buttons of the remote control. And the way to return to a TV channel is as follows: • Pressing INPUT SELECT button at RGB2 input screen. • Pressing some PROGRAM SELECT buttons and select a TV channel. • Pressing PROGRAM UP/DOWN buttons at the screen without OSD(On-screen display). • Input can be switched in the sequence of TV ➔ AV1 ➔ AV2 ➔ AV3 ➔ AV4 ➔ RGB1 ➔ RGB2 by pressing the INPUT SELECT button of the monitor or the remote control. TV AV1 AV2 AV3 RGB2 RGB1 AV4 Downloaded from www.Manualslib.com manuals search engine 16 Size Switching Each time the ZOOM button of the remote control is pressed, the screen display area will change in sequence and the status will be displayed at the bottom of the screen. * Real mode gives the image of the same shape as it is displayed on a computer monitor. This mode is only available for VGA (640 X 480) and WVGA (864 X 480). Normal Full Zoom1 Real Zoom3 Zoom2 D / N A / B i + MENU OK FREEZE ZOOM 2-4-12 I / II P+ P- + - DVD Input Signal Screen Display The input signal status can be displayed on the screen by pressing the RECALL button of the remote control or the monitor. • The display will go out in approximately 6 seconds. RECALL button ZOOM button * Display area selection diagram (RGB input) Resolution Full display Circular display Display Full Normal Real Zoom1 Zoom2 Zoom3 640 X 480 (VGA) 800 X 600 (SVGA) 1024 X 768 (XGA) 1280 X 1024 (SXGA) 1600 X 1200 (UXGA) Processes such as compression (thinning) and expansion are performed for the above signal display. Because of this, there is a possibility that flicker may become noticeable on Zoom (1 ~ 3) depending on the display contents. If this occurs, turning the Vertical Filter On can reduce the flicker. * VGA and W-VGA only 21 RGB2 RGB H : 48.4kHz V : 60.1 Hz -- -- Min. -- -- : -- -- OFF Input mode Signal mode Input horizontal frequency Input vertical frequency Off-timer On-timer RGB Downloaded from www.Manualslib.com manuals search engine 17 ENGLISH Using the Menu Screen (On-screen display system) When the MENU button is pressed, the adjustment menu screen will be displayed; from there, PC signal adjustment and setting is possible by using the SELECT button, ADJUST button and OK button. • Refer to - concerning the adjustment items and the settings. Example: Selecting the Picture screen 1. Press the MENU button to display the Main Menu screen. 2. Press the OK button to display the Picture Menu screen. (Use the and SELECT buttons to select other items.) 3. Use the and SELECT buttons to select the item to be adjusted and then use the and ADJUST buttons to adjust (example: Contrast). • Press the RETURN button to return to the previous screen. • If there is no operation for a period of one minute, the Adjustment Menu screen will be closed automatically. MENU OK Picture Contrast : + 31 Brightness : – 31 Colour : 0 Hue : + 31 Picture Enhancement : Off Colour Temperature : Normal Colour Temp.Adjust Reset Reset Select Return Exit OK P+ P- OPERATING INSTRUCTIONS (continued) Independent Operation of Multiple Monitors (ID No) Setting the ID No. of the remote control allows separate control of up to a maximum of seven monitors. Remote control ID No. 2 (initially ID no. 1) can be set by pressing the ID SET button for 2 sec. or more while holding down the ID button. The number will be incremented (2•••6➔7➔1➔2) when this button pressed continuously. The ID remote control is operated by pressing the various buttons while holding down the ID button; Operation is possible only when the remote control and monitor ID nos. are the same. • The remote control can be operated normally by pressing the various remote control buttons without holding down the ID button. • Set the monitor using the ID No. of Function MENU. Automatic Adjustment of Screen Position and the Clock Adjustment of the screen to a position suitable for the PC signal and the clock adjustment can be performed automatically by pressing the AUTO button of the remote control. * Depending on the signal, satisfactory adjustment may not be possible in some cases. In such case, adjust by referring to the Setup Menu item. ID Number Monitor [ 1 ] R/C [ 1 ] Monitor ID no. Remote control ID no. The remote control ID no. can be checked by pressing the ID SET button while holding down the ID button. Perform this adjustment for each input (RGB1 or RGB2) and for each signal. CAUTION 19 18 22 Picture Audio Timer Function Setup Language Select OK Set Contrast + 31 Next / Prev Adjust Return D / N A / B i + MENU OK FREEZE ZOOM AV1 RGB1 RGB2 AV2 AV3 AV4 2-4-12 I / II P+ P- + - DVD 1 2 3 4 5 6 7 8 0 9 MENU button OK button SELECT/ADJUST buttons RETURN button Downloaded from www.Manualslib.com manuals search engine 18 PICTURE MENU Picture Audio Timer Function Setup Language Select OK Set Picture Contrast : + 31 Brightness : – 31 Colour : 0 Hue : + 31 Picture Enhancement : Off Colour Temperature : Normal Colour Temp.Adjust Reset Reset Select Set Return OK Picture Contrast : + 31 Brightness : – 31 Colour : 0 Hue : + 31 Picture Enhancement : Off Colour Temperature : Normal Colour Temp.Adjust Reset Reset Select Set Return OK OK MENU Picture Colour Temp. Adjust On Amplitude Red – 63 Green 0 Blue – 31 Cut Off Red + 31 Green 0 Blue + 31 Reset Reset Select On/Off Return Contrast + 31 Next / Prev Adjust Return OK Picture Contrast : + 31 Brightness : – 31 Colour : 0 Hue : + 31 Picture Enhancement : Off Colour Temperature : Normal Colour Temp.Adjust Reset Reset Select Set Return OK OK OK Colour Temperature Normal Next / Prev Select Return Selected characters Setup hint Contrast Narrows the gap between brightness and darkness. Broadens the gap between brightness and darkness. Adjust for maximum visibility to suit the ambient brightness. This can adjust further till [+40] by pressing and holding cursor button at [+31]. The colour for [+32] to [+40] numbers will change from white to magenta. This special mode is better for dark scenes. For brighter scene some parts of the picture might not be clear. We recommend to set at [+31]. "Panel Life" in the Function Menu should be set to Normal when Contrast setting is adjusted. Brightness Black is subdued for increased overall darkness. Black is set off for increased overall brightness. Adjust to taste. Colour Darkens colours. Lightens colours. Adjust to taste. Hue Enhances red and weakens green. Enhances green and weakens red. This is not available to adjust when receiving PAL/SECAM signal. In this case the character will be grayed out. Adjust for most realistic skin colour. Picture Enhancement Off Low Middle High Sets the clarity of small details to the desired level. Colour Temperature Cool Normal Warm Black / White Normally set to Normal. Colour Temp. Adjustment Off On Turn On when you wish to change colour temperature depending on the user’s preference. Amplitude Red Brighter scene is decreased in reddish colour. Brighter scene is increased in reddish colour. Adjust colour temperature depending on the user’s preference. These settings are independently stored in each of the 4 Colour Temperature modes. Green Brighter scene is decreased in greenish colour. Brighter scene is increased in greenish colour. Blue Brighter scene is decreased in bluish colour. Brighter scene is increased in bluish colour. Cut Off Red Dark scene is decreased in reddish colour. Dark scene is increased in reddish colour. Green Dark scene is decreased in greenish colour. Dark scene is increased in greenish colour. Blue Dark scene is decreased in bluish colour. Dark scene is increased in bluish colour. Reset (off the function) (waiting to reset) The original factory settings for the items of this Menu page can be restored by pressing the OK button. ▼ ▼ Downloaded from www.Manualslib.com manuals search engine 19 ENGLISH Selected characters Setup hint Audio Mode Movie Music Speech Favourite Movie: This selects the audio suitable for Movie. Music: This selects the audio suitable for Music. Speech: This selects the audio suitable for News, Talk show etc. Favourite: This mode should be adjusted depending on user’s preference. Treble Suppresses treble. Enhances treble. Adjust to taste. Bass Suppresses bass. Enhances bass. Adjust to taste. Balance Suppresses right-side sound. Suppresses left-side sound. Adjust to taste. SRS TruBass Off Low Middle High SRS TruBass takes advance of the ability of the human ear to be able to distinguish between two different tones. By using this ability, TruBass gives enhanced bass sound that otherwise would not be heard. Adjust it depending on the user’s preference. Matrix Surround Off On This features the spacious sound effects of a stadium. Perfect Volume Off On This will automatically adjust volume so each channel and input has the same average volume level. Reset (off the function) (waiting to reset) The original factory settings for the items of this Menu page can be restored by pressing the OK button. Picture Audio Timer Function Setup Language Select OK Set Audio Audio Mode : Movie Treble : + 10 Bass : – 10 Balance : 0 L R SRS TruBass : Middle Matrix Surround : Off Perfect Volume : Off Reset Reset Select Set Return OK MENU AUDIO MENU Picture Audio Timer Function Setup Language Select OK Set Timer Off Timer : 30Min. On Timer : - - : - - Select Adjust Return OK MENU TIMER MENU Selected characters Setup hint Off Timer --Min. 30Min. 60Min. 120Min. 90Min. This function automatically sets the power to standby status when the indicated time period has elapsed. On Timer - - ( : - - ) hours (- - : )- - minutes This automatically sets the power from standby to ON when the indicated time period has elapsed. The settable time is 00:00~11:59. Input the required time by SELECT buttons on the remote control. OPERATING INSTRUCTIONS (continued) ▼ ▼ ▼ ▼ Downloaded from www.Manualslib.com manuals search engine 20 Picture Audio Timer Function Setup Language Select OK Set Function Screen Saver Off Screen Wipe On 60Min. Black Side Panel Off Video Power Save Off Freeze Mode Split Default Zoom Panoramic Reset Reset Select Set Return OK MENU FUNCTION MENU Function Panel Life Normal Mode Display Off ID Number 1 Inverse On 60Min. Standby White Off Gamma 2.2 Reset Reset Select Set Return Selected characters Setup hint Screen Saver Off 5Min. 10Min. 60Min. 40Min. 20Min. This moves the picture around the screen in small amounts, at set intervals, to reduce the panel image retention. This is where stationary objects, such as screen logos, leave a slight image visible after they should have disappeared. Screen Wipe On 60Min. This is used to reduce the panel image retention that can occur with stationary pictures by the white field signal. Select On (continuous operation) or 60 Min. (time limit operation) and press the OK button. Press the MENU or RETURN button on the remote control to return to normal viewing. Black Side Panel Off On This turns the gray sidebars On/Off when watching normal mode screen size area. It is always set to Off when the monitor powered On. It is recommended to set to Off to reduce the panel image retention. Video Power Save Freeze Mode Default Zoom Reset (off the function) (waiting to reset) The original factory settings for the items of this Menu page can be restored by pressing the OK button. Panel Life Normal Extend 1 Extend 2 This function is to suppress the contrast of the screen regardless of the Contrast setting in the Picture Menu. By this control, power consumption can be reduced or degradation of a panel can be mitigated. The order of power consumption is Extend 2 < Extend 1 < Normal. If the Contrast setting is changed when this item is set to Extend 1 or 2, it will be changed to Normal automatically. Mode Display ID Number Inverse Standby White Gamma ▼ ▼ Off On Panoramic 4:3 14:9 Zoom This is used to reduce power consumption for video input when there is no video signal. Setting it On will leads the monitor to the standby mode when the AV input with no signal is selected. This selects the screen display size that appears first when the power turned on. Split Strobe This selects the display condition of the FREEZE mode between Split (2 pictures) and Strobe (12 pictures). Selected characters Setup hint Screen Saver Off 5Min. 10Min. 60Min. 40Min. 20Min. This moves the picture around the screen in small amounts, at set intervals, to reduce the panel image retention. This is wher e stationary objects, such as screen logos, leave a slight image visibl e after they should have disappeared. Screen Wipe On 60Min. This is used to reduce the panel image retention that can occur with stationary pictures by the white field signal. Select On (continuous operation) or 60 Min. (time limit operation) and press the OK button. Press the MENU or RETURN button on the remote control to return to normal viewing. Black Side Panel Off On This turns the gray sidebars On/Off when watching normal mode screen size area. It is always set to Off when the monitor powered On. It is recommended to set to Off to reduce the panel image retention. Video Power Save Freeze Mode Default Zoom Reset (off the function) (waiting to reset) The original factory settings for the items of this Menu page can be restored by pressing the OK button. Panel Life Normal Extend 1 Extend 2 This function is to suppress the contrast of the screen regardless of the Contrast setting in the Picture Menu. By this control, power consumption can be reduced or degradation of a panel can be mitigated. The order of power consumption is Extend 2 < Extend 1 < Normal. If the Contrast setting is changed when this item is set to Extend 1 or 2, it will be changed to Normal automatically. Mode Display ID Number Inverse Standby White Gamma ▼ ▼ Off On Panoramic 4:3 14:9 Zoom This is used to reduce power consumption for video input when there is no video signal. Setting it On will leads the monitor to the standby mode when the AV input with no signal is selected. This selects the screen display size that appears first when the power turned on. (AV4 only) Split Strobe This selects the display condition of the FREEZE mode between Split (2 pictures) and Strobe (12 pictures) . Not Available (grayed out) Not Available (grayed out) Not Available (grayed out) Not Available (grayed out) Not Available (grayed out) Downloaded from www.Manualslib.com manuals search engine Selected characters Setup hint Auto Adjust* (Menu) Adjust Pressing the OK button here, Automatic regulation is started. Horizontal Position, Vertical Position, Horizontal Clock and Clock Phase are adjusted automatically. Horizontal Position Moves the horizontal position to left. Moves the horizontal position to right. Adjust the left-side display position. (This function is only for RGB2. It’s not available (grayed out) for RGB1.) Vertical Position Moves down the vertical position. Moves up the vertical position. Adjust the vertical display position. (This function is only for RGB2. It’s not available (grayed out) for RGB1.) Horizontal Clock Reduces the dot clock frequency (shrinks the right side). Increases the dot clock frequency (expands the right side). Adjust for maximum character clarity. (This function is only for RGB2. It’s not available (grayed out) for RGB1.) Clock Phase Slows the dot clock phase (shifts slightly to left). Advances the dot clock phase (shifts slightly to right). Adjust for clear character visibility. (This function is only for RGB2. It’s not available (grayed out) for RGB1.) Reset (off the function) (waiting to reset) The original factory settings for the items of this Menu page can be restored by pressing the OK button. (This is effective only for RGB2.) Input Level 0.7V 1.0V Normally set to 0.7 V. If white is found to spread across the screen, set to 1.0 V. (This is effective only for RGB2.) Frequency Display Off On Set this to Off if the frequency information of the Input Signal Screen Display is not required. WVGA Type Off On This is only available for W-VGA signal. When it is set to On, the display area modecan be selected Full or Real. Vertical Filter Off On Turn On when concerned about screen flicker. Frequency Mode Movie PC Set to Movie when viewing moving images on a personal computer. RGB1 RGB2 21 ENGLISH SETUP MENU Picture Audio Timer Function Setup Language Select OK Set OK MENU OPERATING INSTRUCTIONS (continued) * Depending on the type of signal displayed, displays may not be optimized through automatic adjustment. Adjust manually to optimize them. ▼ ▼ OK Horizontal Position 0 Next / Prev Adjust Return Clock Phase 10 Next / Prev Adjust Return OK DVI-PC DVI-STB RGB Component This should correspond to the signal mode of the signal from the equipment that is connected to RGB1 DVI terminal. This should correspond to the signal mode of the signal from the equipment that is connected to RGB2 D-sub terminal. Selected characters Setup hint Auto Adjust* (Menu) Adjust Pressing the OK button here, Automatic regulation is started. Horizontal Position, Vertical Position, Horizontal Clock and Clock Phase are adjusted automatically. Horizontal Position Moves the horizontal position to left. Moves the horizontal position to right. Adjust the left-side display position. (This function is only for RGB2. It’s not available (grayed out) for RGB1.) Vertical Position Moves down the vertical position. Moves up the vertical position. Adjust the vertical display position. (This function is only for RGB2. It’s not available (grayed out) for RGB1.) Horizontal Clock Reduces the dot clock frequency (shrinks the right side). Increases the dot clock frequency (expands the right side). Adjust for maximum character clarity. (This function is only for RGB2. It’s not available (grayed out) for RGB1.) Clock Phase Slows the dot clock phase (shifts slightly to left). Advances the dot clock phase (shifts slightly to right). Adjust for clear character visibility. (This function is only for RGB2. It’s not available (grayed out) for RGB1.) Reset (off the function) (waiting to reset) The original factory settings for the items of this Menu page can be restored by pressing the OK button. (This is effective only for RGB2.) Input Level 0.7V 1.0V Normally set to 0.7 V. If white is found to spread across the screen, set to 1.0 V. (This is effective only for RGB2.) Frequency Display Off On Set this to Off if the frequency information of the Input Signal Screen Display is not required. WVGA Type Off On This is only available for W-VGA signal. When it is set to On, the display area modecan be selected Full or Real. Vertical Filter Off On Turn On when concerned about screen flicker. Frequency Mode Movie PC Set to Movie when viewing moving images on a personal computer. RGB1 RGB2 ▼ ▼ DVI-PC DVI-STB RGB Component This should correspond to the signal mode of the signal from the equipment that is connected to RGB1 DVI terminal. This should correspond to the signal mode of the signal from the equipment that is connected to RGB2 D-sub terminal. WXGA Mode This is only available for (PC) WXGA signal.The display area mode is selected [1280x768] or [1366x768]. Off 1280x768 1366x768 Setup Auto Adjust Adjust Horizontal Position 0 Vertical Position + 31 Horizontal Clock – 20 Clock Phase 10 Reset Reset Select Return Exit Setup Auto Adjust Adjust Horizontal Position 0 Vertical Position + 31 Horizontal Clock – 20 Clock Phase 10 Reset Reset Select Return Exit Setup Input Level 0.7V Frequency Display Off WVGA Type Off WXGA Mode Off Vertical Filter On Frequency Mode Movie RGB1 DVI-PC RGB2 RGB Select Set Return Downloaded from www.Manualslib.com manuals search engine 22 LANGUAGE MENU Picture Audio Timer Function Setup Language Select OK Set Language English Français Deutsch Español Italiano Norsk Svenska Select Return Exit OK MENU Select a language by ▼ ▲ SELECT buttons and press the OK button. OTHER FEATURES Automatic Store Approximately 1 sec. after adjustment is completed, the adjustments will be recorded as shown in the table below. Menu Display Registration condition Picture Contrast For every input function, 1 setting is registered. Brightness Colour Hue Picture Enhancement Colour temperature Colour Temp. Adjust R Amplitude For every Colour Temperature, 1 setting is registered. G Amplitude B Amplitude R Cut Off G Cut Off B Cut Off Audio Audio Mode 1 setting is registered. Treble For every Audio Mode, 1 setting is registered. Bass Balance 1 setting is registered. SRS TruBass For every Audio Mode, 1 setting is registered. Matrix Surround Perfect Volume Menu Display Registration condition Function Screen Saver 1 setting is registered. Screen Wipe (not registered) Black Side Panel (not registered) Panel Life 1 setting is registered. Mode Display ID Number Inverse Standby White Gamma Setup Auto Adjust (not registered) Horizontal Position For every signal Mode, 1 setting is registered. (Only for RGB2) Vertical Position Horizontal Clock Clock Phase Input Level 1 setting is registered. Frequency Display WVGA Type Vertical Filter Frequency Mode Language 1 setting is registered. Menu Display Registration condition Function Screen Saver 1 setting is registered. Screen Wipe (not registered) Black Side Panel (not registered) Panel Life 1 setting is registered. Mode Display ID Number Inverse Standby White Gamma Setup Auto Adjust (not registered) Horizontal Position For every signal Mode, 1 setting is registered. (Only for RGB2) Vertical Position Horizontal Clock Clock Phase Input Level 1 setting is registered. Frequency Display WVGA Type Vertical Filter Frequency Mode Language 1 setting is registered. WXGA Mode • The previously recorded items will be lost. • The signal mode can be identified by the horizontal/vertical sync frequency and the sync signal polarity. Different signals with which all the elements are the same or similar will be handled as the same signal. Downloaded from www.Manualslib.com manuals search engine 23 ENGLISH Signal Check Status Display Action When Mode Display is set to ON, the input signal is switched or when the RECALL button is pressed. A guide is displayed for the input terminal and the horizontal and vertical sync frequency. When the sync signal is no longer detected. • A guide displays No Sync. Signal, and Power Save (for approx. 5 sec.) • When the condition continues where the sync signal cannot be detected, indicator lamp of power source changes in orange and the mode switches to power save mode. Recheck the personal computer power switch status and the connection status. When the input signal does not match the monitor specifications or is in an unstable status. A guide displays Invalid Scan Freq. Recheck the input signal specifications. 51 52 ~ ! No Sync. Signal Changes in the signal status are displayed on the screen as they arise. OTHER FEATURES (continued) RGB2 RGB H : 48.4kHz V : 60.1 Hz -- -- Min. -- -- : -- -- OFF RGB ! Invalid Scan Freq. Power Save Mode When the RGB, RGB2 input is selected • When this unit is connected to a VESA DPMS computer, the Power Save (Off) mode can be set to be activated automatically when the computer is not being used to reduce power consumption by this unit. RGB sync signal Horizontal Yes No Yes No Vertical Yes Yes No No PC signal Active (normal display) Blank (no display) Operation mode On Off Indicating lamp Lights green Lights orange Power consumption 310W 3W or less (RGB1) 1W or less (RGB2 ; 100V
