www.pioneer-plasma.com 5 0 ” P D P- 5 0 2 M X E PDP-502MXE Datasheet P R O F E S S I O N A L P L A S M A D I S P L AY Pictured With Optional Table Top Stand (PDK-5001) Large 50” screen True XGA compatibility for pixel perfect image reproduction Wide screen - 16.9 aspect ratio New waffle rib structure for better pixel efficiency, outstanding brightness and stunning picture quality Black stripe screen for improved contrast RS-232 control interface and built-in integrator mode Wide range of mounting brackets and stands Clean, sharp, high resolution image reproduction for video or computer generated data and graphics MacRent Birger Jarlsg 108 114 20 Stockholm http://www.macrent.se Terminal Configuration R SPEAKERS 8Ω -1 6Ω – + AUDIO OUTPUT COMBINATION CONTROL R R L INPUT 1/2 INPUT 3/4 IN OUT IN OUT RS-232C AUDIO INPUT INPUT 4 ANALOG R G B OUTPUT ANALOG R G B ( ( INPUT 3 CB/PB G Y R (ON SYNC) CR/PR B Y R (ON SYNC) HD (H/V SYNC) VD 7.5Ω - 2.2kΩ MAINS POWER AC INLET L SPEAKERS 8Ω -1 6Ω ON / OFF * Component Signal is only accepted when the Video Box (PDA-5001) is connected Input / Output Terminals Standard Display Signal Connector Analogue RGB D-Sub 15 Pin (Input / Output) Component* / RGB BNC RS-232 D-Sub 9 Pin Combination Mini-Din 6 Pin (Input / Output) Control Mini Jack (Input / Output) Audio Stereo Mini Jack / Pin Jack (Input) Audio Stereo Mini Jack (Output) Speaker L/R (Output) Optional Video Box (PDA-5001) Signal Connector Composite / RGB Scart 1 Composite / Y/C Scart 2 Composite BNC (Input / Output) Y/C BNC S-Video S-Video Jack Audio Pin Jack (Input x 2) Dimensions 98 mm 65 mm 1218 mm 1128 mm 628 mm 714 mm 1291 mm Effective Screen Dimensions 1098.2 mm Effective Screen Dimensions 620.5 mm Specifications Effective Screen Size (W x H) 1098.2 x 620.5 mm (50” Diagonal) Aspect Ratio 16:9 Number of Pixels 1280 (Hor) x 768 (Ver) Pixel Pitch 0.858 mm (Hor/RGB trio) x 0.808 mm (Ver) Colour Resolution 256 Grey Scale 16.7 Million Colours Brightness 560 cd/m2 (White Peak) Contrast Ratio 560:1 (Dark Environment) Viewing Angle More Than 160˚(Hor) - 160˚(Ver) Dimensions (W x H x D) 1218 x 714 x 98 mm Weight 40.3 kg Power Consumption 470W (0.6W At Stand By) Power Requirements AC100 - 240V ±10%. 50/60Hz Operating Temperature 0˚C - 40˚C Operating Humidity 20 - 80% Operating Atmospheric Pressure 0.8 - 1.1 Atmospheric Pressure Safety Regulation CE Input Signal Compatibility TV Standard PAL / NTSC / SECAM / HDTV Accessories Accessories Included Remote Control Unit x 1 Remote Control Unit Case x 1 AA(R6) Battery x 2 Speed Clamp x 2 Bead Band x 2 Tabletop Stand x 2 Washer x 4 Hex Bolt x 2 Cleaning Cloth x 1 Operation Manual x 1 Optional Accessories Video Box (PDA-5001) Side Mount Speakers (PDP-S04-LR) 16:9 Graphics Card PCI (PDK-GCP2PCI) 16:9 Graphics Card AGP (PDK-GCP2AGP) Table Top Stand (PDK-5001) Ceiling Bracket (PDK-5002) Wall Bracket (PDK-5005) Tilting Wall Bracket (PDK-5006E/WL) Standard Display VGA / SVGA / XGA* / Compressed SXGA* and UXGA* Personal Computer Input Compatibility * 16:9 Graphics Card Required Pioneer Scandanavia AB Nyckelvägen 2 142 82 Trångsund Sweden Tel: +46 (0) 8 609 91 00 Fax: +46 (0) 8 771 10 15 E-mail: multimedia@pioneer.se www.pioneer.se PDP-502MXE Specifications Design and specification subject to change without notice. All product names and company names are registered trademarks of their respective owners. Published by Pioneer Europe N.V. Multimedia Division. Copyright 1999 by Pioneer Europe N.V. All rights reserved. PLASDATA502-BR-SW MacRent Birger Jarlsg 108 114 20 Stockholm http://www.macrent.se
