维修手册 品牌 机种 Philips 42PFL5300/T3 46PFL5300/T3 26 4.工厂模式调整 一、ADC 调整 按“菜单+1999+返回+确认”进入工厂模式。 以其他机种的工厂模式图片为例： 1. 将“Current Source”切换到“YPbPr”模式并切换信号到 YPbPr Timing 314（720p/60Hz），Pattern 185(COLOR BAR)， 按“Auto Color”。 2. 将“Current Source”切换到“VGA”模式并切换信号到电脑 TIMING 137(1024 x 768), Pattern 42 (5 MOSAIC) 按“Auto Color”. 二、 白平衡调整: 备注: 调整白平衡之前应先将机器先加温至少 30 分钟，需将 CA210 设置到 05 通道并设为 x, y, Y 模式。 以下为白平衡调整的步骤： Color temp x y Y(cd/m2) Normal (7500°K) 0.285 ± 0.010 0.293 ± 0. 010 > 320 Warm (6500°K) 0.305 ± 0. 010 0.315 ± 0. 010 > 320 Cool (9300°K) 0.272 ± 0. 010 0.278 ± 0. 010 > 320 备注: 1. 白平衡调整 VGA 和 YPbPr 两个 source 的 Normal, Cool, Warm 三个色温； 2. 亮度和对比度均设为最大。 27 YPbPr 调整： 首先，按“菜单+1999+返回+确认”进入工厂模式，并将“Current source”切换到“YPbPr”模式； 其次，按“Reset”复位工厂模式里的白平衡； 再次，Gain(增益)调整： 调整 Cool 色温: 1. 通过在 80 IRE (TIMING 314, Pattern 141)信号下调整 R, G, B 的值来调整白平衡； 2. 通过“Color temp”选中其他的色温并调整。 调整 Normal 色温: 1. 通过在 80 IRE (TIMING 314, Pattern 141) 信号下调整 R, G, B 的值来调整白平衡； 2. 通过“Color temp”选中其他的色温并调整。 调整 Warm 色温: 通过在 80 IRE (TIMING 314, Pattern 141)信号下调整 R, G, B 的值来调整白平衡； 选中并按“Exit”退出工厂模式。 VGA 调整 首先，按“菜单+1999+返回+确认”进入工厂模式，并将“Current source”切换到“VGA”模式； 其次，按“Reset”复位工厂模式里的白平衡； 再次，Gain(增益)调整： 调整 Cool 色温: 1. 通过在 80 IRE (TIMING 137, Pattern 141)信号下调整 R, G, B 的值来调整白平衡； 2. 通过“Color temp”选中其他的色温并调整。 调整 Normal 色温: 1. 通过在 80 IRE (TIMING 137, Pattern 141) 信号下调整 R, G, B 的值来调整白平衡； 2. 通过“Color temp”选中其他的色温并调整。 调整 Warm 色温: 通过在 80 IRE (TIMING 137, Pattern 141)信号下调整 R, G, B 的值来调整白平衡； 选中并按“Exit”退出工厂模式。 注: 下页是关于一般工厂菜单的说明(和本机并非完全相同)，仅供参考！ 28 工厂菜单说明 选项名称 调整范围 TV AV/S Comp HD PC 注释 Brand 不可调整 o o o o o 客户名称 Main-MCU ver. 不可调整 o o o o o 发布软体 Main-MCU 版本 Bootloader ver. 不可调整 o o o o o 发布软体 Bootloader 版本 Sub-MCU ver. 不可调整 o o o o o 发布软体 Sub-MCU ver.版本 EEPROM ver. 不可调整 o o o o o 发布软体 EEPROM 版本 Date 不可调整 o o o o o 软体发布日期 Model name 不可调整 o o o o o 对外机种名 Scaler 不可调整 o o o o o Scaler 型号 Panel type 不可调整 o o o o o 屏的型号 Current source 支持输入源 √ √ √ √ √ 当前进工厂时的输入源，该项可切换输入源，对应输入源的 ADC，色温， Scaler 等相关信息同步更新。 Auto color 执行动作 √ √ √ √ √ Auto color 项只对需要做自动校正输入源时有效，否则它不动作。Auto color 会对输入的 ADC 做自动矫正，调整 ADC Gain 和 Offset RGB 值。 ADC Gain 根据 IC SPEC √ √ √ √ √ 在 Auto Color 做完立即更新，并可手动调整。 ADC Offset 根据 IC SPEC √ √ √ √ √ 在 Auto Color 做完立即更新，并可手动调整。 Color temp. 支持色温 √ √ √ √ √ 当前设置的色温，该项可切换色温模式，并正确显示色温名称，对应色温 的 Scaler Gain & Offset RGB 值等相关信息同步更新。 Scaler Gain 根据 IC SPEC √ √ √ √ √ Scaler Gain 值在白平衡调整时立即更新，并可手动调整。 Scaler Offset 根据 IC SPEC √ √ √ √ √ Offset RGB 值在白平衡调整时立即更新，并可手动调整。 Burn in On/Off √ √ √ √ √ 打开或关闭 Burn in 模式。当 Burn in 设置为 On 时它将响应工厂遥控器功 能；EEPROM Init 后默认为 On 状态；Reset 后默认为 Off。 EEPROM Init 执行动作 √ √ √ √ √ 实现的是初始化除了 HDCP key 和产品序列号以外的全部 EEPROM，如 主菜单的 OSD 默认值，工厂菜单的 ADC 数据，白平衡设定值，Black light 和 Language 等，同时把 Burn in 设置为 On，响应工厂遥控器功能，设置 输入源为 TV。 29 Back LIT time 不可调整 o o o o o 背光打开总计时，在 EEPROM Initial 或 Factory reset 后都清为 0，显示 值用十进制表示，当时间到达显示最大值时就不再变化。 Total time 不可调整 o o o o o AC ON 主电源供电总计时，在 EEPROM Initial 或 Factory reset 后都清为 0，显示值用十进制表示，当时间到达显示最大值时就不再变化。 Black light 根据 IC SPEC * * * * * 设置背光灯的亮度 Language 支持语言 * * * * * 设置出厂时用户模式菜单语言，当在工厂菜单中更改此项值时，用户模式 的 OSD 中的菜单语言也做相应的更改并将该值保存（仅北美向可选） Energy LOGO On/Off * * * * * 仅中国向有该项 Reset 执行动作 √ √ √ √ √ 实现的是复位除了 HDCP 和产品序列号，工厂菜单的 ADC 数据，白平衡 设定值，Black light，Language 和 Energy Logo 以外的全部 EEPROM 数 据，如主菜单的 OSD 默认值，并把用户菜单 Language 设置为工厂 Language，同时把 Burn in 设置为 Off，禁止响应工厂遥控器功能，设置 输入源为 TV。 Exit 执行动作 √ √ √ √ √ 退出工厂模式 备注： 1. √表示该项有效, ×表示该项不存在，o 表示存在但选不到，*表示可选； 2. 不同机型工厂模式项目略有增删； 3. 进工厂模式时 Burn in 自动关闭。 30 5.电气方框图 主板方框图 CVBS/AV Out Analog IF+/- SPK STA515W WOOFER AMP 1 Gb DDR2 DDC I2C NVM 24C32 SPI FLASH 64Mb ATV _RF TUNER F86WT-17-E RC UART KEY 24C02 24C02 MT5301BGMU STA339BWTR AUDIO AMP PC IN Digital Audio Output(COIXIAL) SPK RGB YPbPr CVBS VIDEO ( By CVI Y connector) CVI DDC 24C02 24C02 AUDIO R/L (CVI/CVBS) AUDIO IN (PC) HDMI1 TMDS361 BPAGR DDC DDC HDMI3 HDMI2 I2S SPDIF MT8282 MEMC LVDS (50/60 Hz) 1Gb / 1GHz [RX0 : RX3] DDR II X 2 LCD PANEL T-CON Side AV IN LVDS (50/60 Hz) H/Phone Out NOR FLASH 4 Mb USB2 2.0 USB1 2.0 ATV + DTV RF TUNER TDTK-T052D ( RESERVE) Demodulator ATBM8848 ( RESERVE) Analog IF+/- Analog IF+/- NAND FLASH 256Mb LVDS (100/120 Hz) ATV DEMOD HDMI 1.3 TS (SERIAL) 31 主板电源框图 NC DDRV(1.5V) 5V_SW 5V_SW 3V3SB 5VSB LDO G903T63UF U705 5V_SW TUNER 5V_SW V1.2 +12V AO4449 Q709 LVDS_PWR_EN PANEL_VCC M81_DV33 FB6003 +24_SW 5 mA 200 mA U401 MT5301BGMU VCCK (1.2V) AVDD1V2 U408 ADAC_PWR G903T63UF U709 (NC) G903T63UF U707 V3.3 G912T63U U708(NC) V3.3 VDD1V2 BUCK (1.5A) SC189ASK U706 I VCC2IO=900mA I M82_DDRV=550mA I M82_AV12=65mA I M82_V10=928mA I M82_DV33=27mA I M82_AV33=155mA 5V_SW 5V_SW NC/FB DDRV(1V5) +12V BUCK (3A) AOZ1212AI U703 DVDD3V3 DVDD3V3 M81_DDRV M81_AV12 5V_SW LDO G9084TU3U U7007 +B_5V +12V VCCK(1.2V) NVRAM CAT24C128YI U405 NAND FLASH HY27US08561A-TPCB U403 Nor flash MX25L6445 U404 AVDD3V3 USB Connect CN103 CN104 +5V_TUNER STANDBY AO4449 Q708 DV33SB ASIC_3V3 DVDD3V3 De_mod ATBM8848 U101 VDD33 215mA 83mA 5V_SW 5VSB HDMI SW TMDS361BPAGR U501 5VDD 5V_SW AMUX_5V Audio in /SW CD4052 U102 EEPROM CAT24C02YI U105 3V3_BUCK Aud3V3 +24V_AMP Aud_3V3 +24_AMP +24V +12V 5VSB 5V_SW Aud3V3 LDO G903T63UF U607 BUCK (2A) G5657F12U U710 +12V +12V M81_DV11 BUCK (2A) G5657F12U U711 LDO G1117T63UF U712 M81_AV33 M82_AV12 FLASH MX25L4005AMI U4008 LDO G1084-18 U713 M81_DV33 M81_DV33 PANEL_VCC 120Hz PANEL CON CN409 PANEL_VCC 60Hz PANEL CON CN414 DDR2 NT5TU32M16CG-25C 512MB DDR2 NT5TU32M16CG-25C 512MB TU101 (ATV) DDR2 NT5TU64M16DG-BD 1Gb U402 MAX9728AETC+ U606 HP AMP MT8282 +B_5V V3.3 HDMI EEPROM M24C02 U502 U505 U506 DV33_TMDS STA515W U6005 WOOFER AMP STA339BWTR U6003 AUDIO AMP M81_DV11 M81_DV33 AV12_PLL 5V_USB M81_AV33 M82_AV12_MEMPLL M81_DDRV VUSB_5V 5V_SW +24_AMP +24 D6003 BUCK (3A) G5657F12U U704 VCCK(1.2V) 5VSB OPWRSB AO4449 Q707 5V_SW DVDD3V3 BUCK (1.5A) SC189ASKTRT U702 BUCK (1.5A) SC189ASK U702 DVDD3V3 I VCCK :2250 mA I AVDD33=540mA I VCC3IO=200mA I VCC3_STDBY=30mA I AVDD12=400mA 32 6.线路图 6.1 主板（715G4611M0E000004K） Q701 PMBS3904 R769 1K2 1/10W 5% 1 2 ZD139 RLZ5.6B R701 1.2K 1/16W Q703 PMBS3904 R751 0R05 1/10W R710 0R05 1/16W R764 1K 1/16W 5% R752 0R05 1/10W DVDD3V3 R765 NC\1K 1/16W 5% 5V_SW STANDBY R702 NC\10K 1/16W 5% DVDD3V3 R746 NC 4K7 1/16W 5% 1 2 CN416 NC/CONN +12V BL_ON/OFF# BL_DIM_PWM 0% : Max Luma BL_DIM_PWM 99% : Min Luma PWR_OK + C705 100UF 25V R744 10K 1/16W 5% 5VSB 10/7 modifyR712 value + C701 100UF 25V PWR_OK BRI_ADJ BL_CTRL STANDBY LIPS Interface H : ON L : Standby + C703 100UF 35V Brightness Adjust Backlight On/Off PWM Control H : BL_OFF L : BL_ON BRI_ADJ BL_CTRL Q702 NC\2N7002 C706 10U 10V BL_ON/OFF# OEM MODEL Size Rev Date Sheet of TPV MODEL PCB NAME 称爹 T P V ( Top Victory Electronics Co . , Ltd. ) Key Component 絬 隔 瓜 絪 腹 M0B B 4 22 Monday , February 28, 2011 HW4 04 PSU & Inv erter I/F R750 0R05 1/10W C704 100N 50V 1 2 FB702 120R/6000mA 1 2 FB701 120R/6000mA R711 47K 1/16W 5% C707 100N 16V 1 2 3 4 5 6 7 8 9 10 11 12 13 CN701 CONN R706 2.2K 1/16W C702 100N 50V R705 0R05 1/16W R709 1K 1/16W 5% R708 NC\2.2K 1/16W R704 NC\2.2K 1/16W R703 10K 1/16W 5% 1 2 FB703 120R/6000mA R712 0R05 1/10W R707 10K 1/16W 5% C708 NC/1UF 10V +12V 5VSB +24V 3V3_BUCK 5V_SW 5V_SW 5VSB GND 5,6,7,8,9,10,11,12,13,14,15,16,17,18,19,20,21,22 BL_ON/OFF# 12 BL_DIM_PWM 12 PWR_OK 12 STANDBY 12,18 33 R717 10K 1/16W 5% C709 NC\470nF 16V R713 1K 1/16W 5% C762 1UF16V 1 2 FB713 120R/6000mA C710 100N 50V 1 2 FB707 NC\120R/6000mA R714 10K 1/16W 5% R725 56KOHM 1/16W R724 1K 1/16W 5% C715 NC\220NF 25V R716 22K 1/16W 5% S 1 S 2 S 3 G 4 D 8 D 7 D 6 D 5 Q709 AO4449 -7A/-30V 5V_BUCK 5VSB +12V 5VSB VCCK LVDSVDD 5V_SW R727 10K 1/10W LVDS_PWR_EN 12 5VSB R740 4K7 1/16W 5% System Power Control LVDS_PWR_EN 1 2 FB734 NC 120R/3000mA NC 1V2: ON 0V: STANDBY LVDS_PWR_EN YES YES NC NC NC FB712 FB713 12V panel 5V panel Q704 PMBS3904 FB711 Q706 PMBS3904 5VESD L: Off H: On Panel Logic Power Control 1 2 FB735 NC\120R/3000mA 3V3 Main Power : OEM MODEL Size Rev Date Sheet of TPV MODEL PCB NAME 称爹 T P V ( Top Victory Electronics Co . , Ltd. ) Key Component 絬 隔 瓜 絪 腹 M0B D 5 22 Monday , February 28, 2011 HW4 05. DC-DC BUCK & LDO Regulator 1 2 FB746 120R/3000mA C725 10N 50V R735 20K 1/16W C724 10U 16V L703 10uH C744 180pF 50V C737 10U 16V 1 2 FB726 120R/6000mA R742 10K +-1% 1/16W R731 1K 1/16W 5% 1 2 D703 NC RB160M-60TE25 L702 2.2uH C727 10U 16V LX 3 FB 5 SS 8 IN 2 EN 7 COMP 6 NC 1 GND 4 Thermal Pad 9 U704 G5657F12U R733 10K +-1% 1/16W 1 2 FB718 120R/3000mA C735 100N 50V R743 2.7K 1/16W 1% C747 100N 16V C734 1uF 16V C728 10U 16V LX 1 BST 2 GND 3 FB 4 COMP 5 EN 6 VIN 7 VBIAS 8 U703 AOZ1212AI 1 2 FB717 120R/3000mA C730 1uF 50V R737 15K 1% C749 10U 16V 1 2 FB725 120R/3000mA C723 1UF 10V C739 1UF 10V C726 10N 50V C746 NC 10N 50V 1 2 D704 SX34 C742 10U 16V VOUT 4 VIN 1 EN 3 LX 5 GND 2 U702 SC189ASKTRT R732 8.2K 1% C745 2.2nF 50V C722 1UF 10V 1 2 FB716 120R/3000mA C732 180pF 50V 1 2 FB719 120R/3000mA 1 2 D702 SX34 R736 82K 1/16W C736 10U 16V C741 10U 16V C733 1nF 50V R741 12KOHM +-5% 1/16W R734 47K 1/16W 5% C748 10U 16V 5V_BUCK +12V 3V3_BUCK DVDD3V3 AVDD3V3 5VSB VCCK 3V3_BUCK R736 = 220K R736 = 82K 5V_SW 5V_USB DDRV R743 = 2.7K --> 2.43K C7002 NC\100N 16V C743 100N 16V 12V5 or 5V2 Main Power (3A) 1 2 FB721 120R/3000mA L704 47uH 3V3SB AMP = ? mA MUX = ?mA R745 1K 1/16W 5% OPWRSB 1 2 FB723 120R/3000mA USB2.0 = 1000mA R768 NC\0.68 OHM +-5% 2WS 1 2 FB728 120R/3000mA GND 4,6,7,8,9,10,11,12,13,14,15,16,17,18,19,20,21,22 +24V_USB OPWRSB 12 OPWRSB + C729 100UF 25V Demod_1V2 = 210mA Vout=Fixed 1.2V NC G912T63U NC G903T63UF Demod 3V3 Power : V3.3 Vout=Fixed 3.3V Demod_3V3 = 85mA. C763 NC\10U 16V C764 NC\1UF 10V C767 NC\10U 16V VIN 3 VOUT 2 GND 1 4 4 U709 1 2 FB736 NC\120R/3000mA 5V_SW ADAC_PWR NC/G903T63UF VI 3 VO 2 GND 1 4 4 U708 Vout=Fixed 3.3V Reserved for ADAC_PWR C757 NC 10U 16V C751 10U 16V 1 2 FB733 NC 120R/3000mA C760 NC 10U 16V C750 1UF 10V C756 NC 1UF 10V C759 NC 1UF 10V C752 10U 16V VIN 3 VOUT 2 GND 1 4 4 U707 1 2 FB731 NC 120R/3000mA C761 NC\10U 16V VIN 3 VOUT 2 GND 1 4 4 U705 C758 NC\10U 16V 1 2 FB727 120R/3000mA 3V3SB V3.3 V1.2 V3.3 5VSB 5V_SW Demod 1V2 Power : V1.2 SoC_AVDD1V2 = 400 mA Analog Power : AVDD1V2 1 2 FB737 120R/3000mA AVDD3V3 SoC_X'TAL = 80 mA; SoC_3V3_STBC = 30 mA; Vout=Fixed 3.3V Total = 110 mA. STBY Power : 3V3SB G903T63UF C753 10U 16V L705 2.2uH C754 10N 50V R748 10K +-1% 1/16W R747 1K 1/16W 5% C766 10U 16V C765 10U 16V 1 2 FB729 120R/3000mA VOUT 4 VIN 1 EN 3 LX 5 GND 2 U706 SC189ASKTRT 1 2 FB730 120R/3000mA C755 10N 50V R749 2K 1% 5V_SW AVDD1V2 V1 = 1+ (2/10) = 1.2 Vo = 1+ (R749/R748) DC-DC Buck &Converter HDMI_SW = 120 mA SoC_AVDD3V3 = 740 mA C731 1uF 50V DDR3 = 900mA R723 10K 1/16W 5% 1 2 FB732 NC 120R/3000mA 1 2 FB715 120R/6000mA LDO Regulator 1V8 or 1V5 DDR Power : DDRV 15K 220K 82K 12V5 5V2 Power MOSFET Switch R736 R737 15K V1 = 0.8 * (1+ 220/15) = 12.5 V2 = 0.8 * (1+ 82/15) = 5.17 V1 = 1+ (8.2/10) = 1.82 V2 = 1+ (5.2/10) = 1.52 DDR2 = 650mA Vo = 1+ (R732/R733) Vo = 0.8 * (1+ R736/R737) R732 = 2.7K --> 8.2K R732 = 2.7K --> 5.2K Vout=0.827x (1+100.3K/33K) = 3.34V for DVDD3V3 & AVDD3V3 R729 180K 1% VIN 1 VIN 2 GND 3 GND 4 AGND 5 VSNS 6 COMP 7 RT/CLK 8 SS 9 PH 10 PH 11 PH 12 BOOT 13 PWRGD 14 EN 15 VIN 16 PwPd 17 U701 TPS54319RTE C713 3.3nF 50V R730 300R 1/16W 1% C720 22uF 10V R767 100K 1% C738 0.1UF 16V L701 1.5UH TP708 R728 7K5 1/16W 5% C719 NC/22uF 10V C721 22uF 10V R766 33K 1% R772 100K 1/16W 5% C799 0.1UF 16V C717 10uF 10V C718 100N 16V C7001 100N 16V 3V3_BUCK 5V_SW Vo = 0.925*(1+R743/R742) = 0.925*(1+2.43/10) = 1.15 R753 10K +-1% 1/16W Soc Core Power : 1.15V (3A) SoC_1V2 = 2250mA C716 100N 50V R715 10K 1/16W 5% 1 2 FB714 NC/120R/6000mA S 1 S 2 S 3 G 4 D 8 D 7 D 6 D 5 Q707 AO4449 -7A/-30V 1 2 FB712 NC/120R/6000mA C714 220NF 25V R726 56KOHM 1/16W 1 2 FB711 NC\120R/6000mA 34 R189 4K7 1/16W 5% C136 10U 16V URSW VGA_R_IN VGA_L_IN VGACOM SOG GP DDC_WP# 1 2 ZD118 NC\MLVG0402 1 2 ZD117 NC\MLVG0402 VGA_SDA HSYNC VSYNC RP BP VGA_RX C132 10N 50V VGA_SCL PC_5VI VGA Input R165 0R05 1/16W C133 10N 50V R166 0R05 1/16W A 1 K 2 D102 NC\BAS316 H : Write L : WP C134 10N 50V URSW RX/TX E_SW 1 3 2 Q106 NC BC847C R169 NC 4K7 1/16W 5% R167 NC 10K 1/16W 5% U0RX VGA_RX VGA_TX U0TX R168 NC 100R 1/16W 5% Q1008 NC 2N7002 R210 100R 1/16W 5% R170 100R 1/16W 5% Q1009 NC 2N7002 5V_SW C137 10U 16V 3V3SB Q105 PMBS3904 9/24 DEL UART WB adjustment , add RX/TX E_SW OEM MODEL Size Rev Date Sheet of TPV MODEL PCB NAME 称爹 T P V ( Top Victory Electronics Co . , Ltd. ) Key Component 絬 隔 瓜 絪 腹 M0B Custom 6 22 Monday , February 28, 2011 HW4 06. VGA & PC Line-in VGA_R VGA_R_IN VGA_L_IN R184 NC\2K 1/16W Close to SoC Close to Jack R186 10K 1/16W 5% 1 2 FB110 30R/700mA R190 NC/1K1/16W C119 1.5nF 50V R163 75R 1/16W 1% R173 10K 1/16W 5% C116 NC\10P 50V R158 68R 1/16W 5% VGA_B 1 2 FB109 30R/700mA 1 2 FB107 120R/3000mA 1 2 ZD121 NC\MLVG0402 PC_SDA C139 22P 50V VS HS PC_SCL C135 100N 16V R159 75R 1/16W 1% C118 10N 50V R182 NC\2K 1/16W R187 10K 1/16W 5% C140 100N 16V R185 10K 1/16W 5% R174 10K 1/16W 5% C117 NC\10P 50V C115 NC\10P 50V C138 22P 50V R175 5.1K 1% Close to SoC 1 2 FB108 30R/700mA Close to Jack R157 75R 1/16W 1% 1 2 ZD122 NC\MLVG0402 VGA_5V AMUX_5V 5V_SW VGA_5V VGA_L_IN 7 GND 4,5,7,8,9,10,11,12,13,14,15,16,17,18,19,20,21,22 GP 12 HSYNC 12 VSYNC 12 VGA_R_IN 7 BP 12 VGACOM 12 RP 12 VGA_SCL 12 SOG 12 VGA_SDA 12 PC_SDA DDC_WP# 8,12 R172 0R05 1/10W A0 1 A1 2 A2 3 GND 4 SDA 5 SCL 6 WP 7 VCC 8 U105 CAT24C02YI-GT3 R176 5.1K 1% VGA_R 1 6 2 7 3 8 4 9 5 11 12 13 14 15 10 17 16 CN101 D-SUB 15P A 1 K 2 D103 NC\BAS316 1 2 ZD123 NC\MLVG0402 R177 470K 1/16W 5% 1 2 3 CN102 PHONEJACK MT5301B support Embedded VGA EDID EEPROM VGA_G PC_SCL D101 BAT54C R178 470K 1/16W 5% VGA_TX BP RP SOG VGACOM GP 1 2 ZD130 NC\MLVG0402 1 2 ZD129 NC\MLVG0402 VSYNC HSYNC HS VS R179 470K 1/16W 5% 1 2 ZD124 NC\MLVG0402 VGA_B R188 1K 1/16W 5% R180 470K 1/16W 5% VGA SYNC Slicer PC_SDA 5VESD A 1 K 2 D106 NC\BAS316 PC_AU_INR PC Audio-in 1 2 ZD119 NC\MLVG0402 1 2 ZD120 NC\MLVG0402 VGA_G HS R161 68R 1/16W 5% PC_SCL R162 100R 1/16W 1% 1 2 ZD125 NC\MLVG0402 1 2 ZD126 NC\MLVG0402 DDC_WP# 1 2 ZD128 NC\MLVG0402 1 2 ZD127 NC\MLVG0402 R164 68R 1/16W 5% PC_5VI R160 0R05 1/16W R171 0R05 1/10W 35 AMUX_5V 5VESD VGA_L_IN CVBS_COM 5V_SW R104 68R 1/16W 5% C110 10N 50V R103 75R 1/16W 1% C112 10U 16V CVI & rear AV AIN_CTL0 AIN_CTL1 Close to SoC PC Line-in AV1 (Side) Audio-in MUX Select Table (Reserved) R105 0R05 1/16W 0 0 0 1 1 1 1 0 AV1_RIN VGA_R_IN AV Input (Side) Close to RCA CVI_L_IN1 CVI_R_IN1 AUD_ROUT AIN0_L_AADC MUX_CTLB MUX_CTLA OEM MODEL Size Rev Date Sheet of TPV MODEL PCB NAME 称爹 T P V ( Top Victory Electronics Co . , Ltd. ) Key Component 絬 隔 瓜 絪 腹 M0B Custom 7 22 Monday , February 28, 2011 HW4 07. AVI1 & AV2 & Audio-in MUX R228 0R05 1/4W R230 0R05 1/4W R229 0R05 1/4W R232 0R05 1/4W R231 0R05 1/4W AIN_CTL1 MUX_CTLB MUX_CTLA Audio-in MUX AIN_CTL0 1 2 ZD104 NC\MLVG0402 AUD_LOUT Audio-in MUX CTRL AIN0_R_AADC C109 10N 50V R110 470K 1/16W 5% 1 2 FB106 120R/3000mA C111 10U 16V Y2 2 Y0 1 VEE 7 INH 6 CTL_B 9 CTL_A 10 Yout 3 X0 12 X3 11 VSS 8 Y3 4 Xout 13 X1 14 VDD 16 X2 15 Y1 5 U102 CD4052BPW X R102 0R05 1/10W CTL_B CTL_A 1 1 0 0 3x, 3y 1 1 1x, 1y 0x, 0y 0 None X 2x, 2y 0 AV1_CVBS CVBS_COM C106 NC\220pF 50V R101 0R05 1/10W AMUX_5V AMUX_5V AMUX_5V AMUX_5V AV1_CVBS 12 Close to IC CVI_L_IN1 CVI_R_IN1 CVBS_COM 12 VGA_R_IN 6 AIN_CTL1 12 AIN_CTL0 12 VGA_L_IN 6 AIN0_L_AADC 12 AIN0_R_AADC 12 CVI_L_IN1 CVI_R_IN1 AV1_R R148 68R 1/16W 5% R138 100R 1/16W 5% 1 2 FB111 30R/700mA C146 22P 50V 1 2 FB112 30R/700mA R181 68R 1/16W 5% PB1P C147 22P 50V 1 2 ZD114 NC\MLVG0402 C148 10U 16V 1 2 ZD115 NC\MLVG0402 1 2 ZD116 NC\MLVG0402 1 2 ZD132 NC\MLVG0402 C149 1500P50V R183 5.1K 1% R111 470K 1/16W 5% C150 10U 16V CVBS R199 18R 1/16W 5% Close to SoC R200 5.1K 1% CVI1_R_IN C151 10N 50V AV2_CVBS 12 C152 15PF50V AV2_CVBS R205 18R 1/16W 5% SOY1 GND 4,5,6,8,9,10,11,12,13,14,15,16,17,18,19,20,21,22 COM1 PR1P PB1P SOY1 12 Y1P 12 COM1 12 Y1P PR1P 12 PB1P 12 CVI_R_IN1 CVI_L_IN1 CVI_R_IN1 CVI_L_IN1 C153 15PF50V R212 10K 1/16W 5% C154 10N 50V AV2_CVBS C155 47nF 16V R213 68R 1/16W 5% C156 47pF 50V R214 0R05 1/16W CVBS R215 56R 1/16W 5% C157 10N 50V 1 2 ZD133 NC\MLVG0402 R/L-in INHIBIT Video-in Close to RCA Close to RCA CVI_R_IN1 PR1 Close to IC CVI_L_IN1 CVI (Rear) Y1 AMUX_5V C158 10N 50V R216 56R 1 2 FB113 30R/700mA 1 2 ZD134 NC\MLVG0402 R217 0R05 1/16W COM1 CVI1_L_IN PR1P R112 470K 1/16W 5% SOY1 Y1P 5VESD 5VESD C159 15PF50V R218 470K 1/16W 5% R219 68R 1/16W 5% 1 2 ZD135 NC\MLVG0402 R223 470K 1/16W 5% R222 10K 1/16W 5% 5VESD R225 18R 1/16W 5% R224 470K 1/16W 5% R227 470K 1/16W 5% R226 56R 1/16W 5% 1 2 ZD136 NC\MLVG0402 C101 10U 10V R/L-in R113 470K 1/16W 5% PB1 CVBS-in R106 10K 1/16W 5% 1 2 FB101 120R/3000mA VGA_R_IN VGA_L_IN 2 1 4 3 5 6 A B C CN121 RCA JACK 6P C104 10U 16V 1 2 ZD103 NC\MLVG0402 R107 10K 1/16W 5% AV1_CVBS 1 2 ZD102 NC\MLVG0402 1 2 3 4 5 6 7 8 9 10 E A B C D CN702 RCA JACK R115 10K 1/16W 5% C102 100N16V 1 2 ZD105 NC\MLVG0402 R108 5.1K 1% 0 C107 47nF 16V R114 10K 1/16W 5% AV1_L 0 C105 10U 16V R126 10K 1/16W 5% Q101 PMBS3904 0 C103 100N16V R109 5.1K 1% AIN0_R_AADC AIN0_L_AADC AIN_CTL1 0 AIN_CTL0 1 AV1_LIN AV1_RIN Q102 PMBS3904 AV1_LIN R128 10K 1/16W 5% C108 47nF 16V 36 R559 NC 100R 1/16W 1% VDD: HPD/DDC pw r supply RX1_0B HDMI_SCL R560 NC 100R 1/16W 1% RX1_2 LP# H: normal mode LP# L: low pw r state 5VDD HDMIB_SDA RXC_2- RXB_0+ DV33_TMDS RXB_1- DV33_TMDS RXC_1+ HPD_B RXC_C+ RXB_1+ HDMIB_SCL RXB_2+ S2_SDA S1_SCL RXB_C- RXB_2- HDMI_SDA RXC_1- RXB_C+ RXC_C- RXA_1+ RXA_C+ DV33_TMDS DV33_TMDS HDMIC_SCL RXA_0+ HDMIA_SDA HDMIA_SCL RXA_1- RXA_C- DV33_TMDS HDMI_SCL RXA_2+ HPD_A HDMI_HPD1 VS_ADJ HDMIC_SDA DV33_TMDS RX1_1 DV33_TMDS DV33_TMDS RXC_0+ RXB_0- RX1_2 RX1_2B RX1_1B RX1_C RX1_CB EQ_I2C_SEL RXC_0- HPD_C RXC_2+ 5VDD_LP# RX1_0 RX1_0B SDA3 1 SCL3 2 GND 3 CLK-_3 4 CLK+_3 5 VCC 6 D0-_3 7 D0+_3 8 GND 9 D1-_3 10 D1+_3 11 VCC 12 D2-_3 13 D2+_3 14 GND 15 VSadj 16 D2+_SINK 17 D2-_SINK 18 VCC 19 D1+_SINK 20 D1-_SINK 21 GND 22 D0+_SINK 23 D0-_SINK 24 VCC 25 CLK+_SINK 26 CLK-_SINK 27 GND 28 SCL_SINK 29 SDA_SINK 30 HPD_SINK 31 S1/SCL 32 S2/SDA 33 I2C_SEL 34 HPD1 35 SDA1 36 SCL1 37 CLK-_1 38 CLK+_1 39 VCC 40 D0-_1 41 D0+_1 42 GND 43 D1-_1 44 D1+_1 45 VCC 46 D2-_1 47 D2+_1 48 LP 49 HPD2 50 SDA2 51 SCL2 52 CLK-_2 53 CLK+_2 54 VCC 55 D0-_2 56 D0+_2 57 GND 58 D1-_2 59 D1+_2 60 VCC 61 D2-_2 62 D2+_2 63 HPD3 64 TMDS361BPAGR U501 H : GPIO L : I2C TMDS351 S2 S1 PIN 33 PIN 32 TMDS361B SCL SDA NC 4.02k 4.7k TMDS351 4.02k R511 R513 4.7k R534 TMDS361B 0R NC R510 NC NC IT6633T 0R 0R NC RX1_2 4.7k NC R532 NC HDMIB_SCL R547 1K 1/16W 5% R528 0R05 1/10W HD5V_B 5V_SW R548 10K 1/10W Q507 PMBS3904 D516 BAT54C RXB_C- CEC_B RX1_CB R535 100R 1/16W 5% RXB_2+ R536 100R 1/16W 5% RXB_1+ R540 470K 1/16W 5% R539 1K 1/16W 5% R538 4K7 1/16W 5% R537 1K 1/16W 5% HPD_B RXB_1- A 1 K 2 D510 NC\BAS316 A 1 K 2 D512 NC\BAS316 RXB_0+ A 1 K 2 D511 NC\BAS316 RXB_0- RXB_C+ 1 2 ZD505 NC BZX384-C5V6 A0 1 A1 2 A2 3 GND 4 SDA 5 SCL 6 WP 7 VCC 8 U505 CAT24C02YI-GT3 HDMI B EDID EEPROM DDC_WP# PWR5V_B C515 100N 16V Q505 PMBS3904 5VDD_LP# H : Write L : WP RXB_2- R551 1K 1/16W 5% HDMIB_SDA R550 4K7 1/10W 5% HD5V_B HDMI B R549 4K7 1/10W 5% 1 2 FB504 120R/3000mA TMDSD0+ 7 TMDSD0- 9 TMDSD1+ 4 TMDSD1- 6 TMDSD2+ 1 TMDSD2- 3 SCL 15 DSHLD1 5 VCC5 18 CSHLD0 11 HPD 19 NC 14 DSHLD0 2 CEC 13 SDA 16 DDC_GND 17 DSHLD2 8 TMDSC+ 10 TMDSC- 12 SHLD0 20 SHLD1 21 SHLD2 22 SHLD3 23 CN507 HDMI C513 100N 16V RX1_1B RXA_0- HDMI_CEC R531 0R05 1/16W SPDIF_OUT R530 0R05 1/16W PWR5V_C U501 DDC_WP# 6,12 PWR5V_C 12 PWR5V_B 12 DDC_WP# PWR5V_B C501 10U 10V DV33_TMDS OEM MODEL Size Rev Date Sheet of TPV MODEL PCB NAME 称爹 T P V ( Top Victory Electronics Co . , Ltd. ) Key Component 絬 隔 瓜 絪 腹 A Custom 8 22 Monday , February 28, 2011 HW4 08. HDMI A & Switch 3:1 1 2 FB502 120R/3000mA R512 10K 1/10W R509 NC\0R05 1/16W R511 NC 4.7K1/16W R522 NC 0R05 1/16W 1 2 FB501 120R/3000mA C505 100N 16V C506 100N 16V R507 0R05 1/16W C502 100N 16V A 1 K 2 D504 BAS316 C509 100N 16V RXA_2- 1 2 ZD502 NC\MLVG0402 R569 NC 10K 1/16W 5% R519 10K 1/10W C508 100N 16V R572 NC 82R 1/10W 5% ARC R508 27K 1/10W 5% C511 NC 1UF16V OE 1 A 2 GND 3 Y 4 VCC 5 U412 NC SN74LVC1G125DBVR SPDIF_OUT R571 NC 180OHM 1/10W ARC R573 NC 100K 1/10W 5% R513 4.02K 1% C507 100N 16V ARC_ON R521 NC 0R05 1/16W C503 10U 10V DVDD3V3 R570 NC\10K 1/16W 5% R532 NC\10K 1/10W R510 4.7K1/16W C504 100N 16V R520 10K 1/10W 5VDD 5V_SW DV33_TMDS DV33_TMDS AVDD3V3 3V3SB 3V3SB DV33_TMDS M_RX1_CB 12 5VDD M_RX1_1B 12 M_RX1_0 12 M_RX1_0B 12 M_RX1_C 12 M_RX1_2 12 M_RX1_2B 12 M_RX1_1 12 HDMI_SDA 12 GND 4,5,6,7,9,10,11,12,13,14,15,16,17,18,19,20,21,22 HDMI_CEC 12 PWR5V_A 12 HDMI_HPD1 12 HDMI_SCL 12 DDC_WP# 6,12 OSDA0 S1_SCL S2_SDA OSCL0 HDMI_S2 PIN 34 HDMI_S1 R534 4.7K1/16W HDMI_S1 12 OSCL0 9,10,12,13,18,20 OSDA0 9,10,12,13,18,20 HDMI_S2 12 RX1_2B PIN 49 SPDIF_OUT 12,17 Near HDMI switch (U501) RX1_0 <10pF CEC_B CEC_A HDMI_CEC CEC_C A0 1 A1 2 A2 3 GND 4 SDA 5 SCL 6 WP 7 VCC 8 U502 CAT24C02YI-GT3 HDMI A EDID EEPROM Q501 PMBS3904 DDC_WP# HDMIA_SCL R514 1K 1/16W 5% PWR5V_A HDMI_SDA RXA_C- R501 100R 1/16W 5% SCL_A CEC_A SDA_A RXA_2+ R502 100R 1/16W 5% R503 1K 1/16W 5% RXA_1+ R504 470K 1/16W 5% R506 4K7 1/16W 5% R505 1K 1/16W 5% RXA_1- HPD_A RXA_0- A 1 K 2 D501 NC\BAS316 A 1 K 2 D503 NC\BAS316 A 1 K 2 D502 NC\BAS316 HDMI A RXA_0+ 1 2 ZD501 NC\BZX384-C5V6 RXA_2- RXA_C+ R517 4K7 1/10W 5% ARC R515 10K 1/10W C512 100N 16V HDMIA_SDA R526 0R05 1/10W H : Write L : WP D505 BAT54C Q503 PMBS3904 C510 100N 16V R516 4K7 1/10W 5% 5V_SW HD5V_A R518 1K 1/16W 5% 1 2 FB503 120R/3000mA TMDSD0+ 7 TMDSD0- 9 TMDSD1+ 4 TMDSD1- 6 TMDSD2+ 1 TMDSD2- 3 SCL 15 DSHLD1 5 VCC5 18 CSHLD0 11 HPD 19 NC 14 DSHLD0 2 CEC 13 SDA 16 DDC_GND 17 DSHLD2 8 TMDSC+ 10 TMDSC- 12 SHLD0 20 SHLD1 21 SHLD2 22 SHLD3 23 CN506 HDMI R557 NC 100R 1/16W 1% 1 2 FB505 120R/3000mA RX1_CB HDMIC_SDA HDMIC_SCL HD5V_C D604 BAT54C C516 100N 16V R555 4K7 1/10W 5% R542 100R 1/16W 5% A 1 K 2 D514 NC\BAS316 R546 470K 1/16W 5% A 1 K 2 D515 NC\BAS316 R543 1K 1/16W 5% R544 4.7K1/16W R541 100R 1/16W 5% R552 1K 1/16W 5% R545 1K 1/16W 5% A 1 K 2 D513 NC\BAS316 HD5V_C 5V_SW R533 0R05 1/10W HDMI C EDID EEPROM DDC_WP# PWR5V_C R554 4K7 1/10W 5% Q506 PMBS3904 R553 10K 1/16W 5% Q508 PMBS3904 H : Write L : WP R556 1K 1/16W 5% A0 1 A1 2 A2 3 GND 4 SDA 5 SCL 6 WP 7 VCC 8 U506 CAT24C02YI-GT3 1 2 ZD506 NC\BZX384-C5V6 RXC_2+ RX1_C RXC_0+ RXC_1- RXC_1+ RXC_2- CEC_C RXC_C- RXC_C+ RXC_0- HPD_C HDMI C SHLD0 20 SHLD1 21 TMDSD2+ 1 DSHLD0 2 TMDSD2- 3 TMDSD1+ 4 DSHLD1 5 TMDSD1- 6 TMDSD0+ 7 DSHLD2 8 TMDSD0- 9 TMDSC+ 10 CSHLD0 11 TMDSC- 12 CEC 13 NC 14 SCL 15 SDA 16 DDC_GND 17 VCC5 18 HPD 19 SHLD2 22 SHLD3 23 CN508 HDMI C514 100N 16V HDMI_S1 HDMI_S2 R558 NC 100R 1/16W 1% RX1_0B EQ_I2C_SEL Near IC VS_ADJ HDMI_HPD1 PWR5V_A HDMI_SDA HDMI_SCL HDMI_HPD1 DDC_WP# RX1_0 RX1_1B RX1_1 OSCL0 OSDA0 EQ H: 10m EQ L: HDMI 1.3 HD5V_A RX1_C RX1_2B I2C_SEL H: GPIO I2C_SEL L: I2C RX1_1 Q502 NC\2N7002 ARC_ON 12 ARC_ON 37 Tuner TU101 : CCM :DTI8-C40II(D+A) LG :TDTK-G902D(D+A) TCL :DTC86WT-2-E (D+A) TCL :F86WT-2-E "094G PAL D 8L " (A only, ) TU_5V_SDA 1 2 3 Q1109 NC\PMBS3906 C1159 NC\100N 16V TU_SDA TU_SCL TU_SDA BPF_IF- OSCL0 TIF+ Tuner _I2C 3.3V to 5V T2D_TIF- BST_CTL# RFAGC_I R1153 27R 1/16W 5% TIF- Q1101 NC\PMBS3904 C1165 NC\100N 16V Near Tuner R1153 & R1154 0R 1 2 3 Q1106 PMBS3906 G702D 27R 27R R1155 & R1156 0R R1154 27R 1/16W 5% T032D R1150 NC\0R05 1/16W IF_AGC_D2T R1158 10K 1/16W 5% R1166 10K 1/16W 5% R1148 100K 1/16W 5% +B_5V IF_AGC_S2T R1147 NC\0R05 1/16W T2D_TIF+ 10 T2D_TIF- 10 T2D_TIF- T2D_TIF+ 1 2 L1102 NC\22uH TIF- 460R Scaler IC MT5301D MT5301B 100R 50R 220pF / 100uH R1159 & R1160 C1155 / L1111 NC / NC Tuner R1155 27R 1/16W 5% R1192 NC\20K 1/16W 5% R1156 27R 1/16W 5% TU_5V_SDA TIF+ RF_AGC_CTL 10 RF_AGC_CTL OEM MODEL Size Rev Date Sheet of TPV MODEL PCB NAME 称爹 T P V ( Top Victory Electronics Co . , Ltd. ) Key Component 絬 隔 瓜 絪 腹 M0B Custom 9 22 Monday , February 28, 2011 HW4 09. Half NIM Tuner 1 2 3 Q1108 PMBS3906 Q1107 PMBS3904 IF_AGC_SW VCC1 1 RF AGC 2 Tu 3 SCL 4 SDA 5 AIF1 6 AIF2 7 TH1 8 TH2 9 TH3 10 TH4 11 TU103 NC\TAF16-C2I1LH R1184 NC\0R05 1/16W For DTV only R1186 NC\0R05 1/16W TIF+ TIF- RF_AGC_S2T R1157 100R 1/16W 5% R1133 0R05 1/16W R1131 0R05 1/16W R1141 0R05 1/16W R1132 0R05 1/16W C1147 47nF 16V R1144 NC\0R05 1/16W OSDA0 C1152 10N 50V R1152 10K 1/16W 5% OSCL0 R1137 NC\4K7 1/16W 5% IF_AGC_S2T IF_AGC_D2T DTMB_DVBC_SW R1136 NC\4K7 1/16W 5% R1140 4K7 1/16W 5% Tuner = 450mA C1155 220pF 50V C1143 22pF 50V Q1102 2N7002 C1151 NC 100pF 50V C1142 22pF 50V R1146 NC\0R05 1/16W C1150 NC 100pF 50V R1143 4K7 1/16W 5% R1130 0R05 1/16W C1154 NC 100P 50V R1139 100R 1/16W 5% R1138 100R 1/16W 5% R1145 0R05 1/16W R1142 NC\0R05 1/16W +B_5V V3.3 +B_5V V3.3 V3.3 +B_5V 5V_SW +B_5V 5V_TUNER GND 4,5,6,7,8,10,11,12,13,14,15,16,17,18,19,20,21,22 OSCL0 8,10,12,13,18,20 OSDA0 8,10,12,13,18,20 DTMB_DVBC_SW 12 IF_AGC_D2T 10 IF_AGC_S2T 12 TU_SCL 10 T2S_TIF- 12 T2S_TIF+ 12 RF_AGC_S2T 12 TU_SDA 10 TU_5V_SCL C1153 10N 50V C1158 NC\100N 16V A Tuner : NC BPF_IF- R1187 NC\0R05 1/16W R1161 0R05 1/10W R1177 NC\100K 1/16W 5% R1191 100K 1/16W 5% RFIN_CTL C1157 NC\100N 16V For ATV only 1 2 FB724 NC\120R/3000mA IF_AGC_SW 10 IF_AGC_SW Q1103 2N7002 C1166 NC\100N 16V +B_5V TU_5V_SCL TU_5V_SDA TIF- TIF+ TU_5V_SCL TU_5V_SDA +B_5V A Tuner : IFAGC_T RFAGC_I L1103 0.1uH RFAGC_I BPF_IF+ R1189 NC\0R05 1/16W N.C 1 N.C 2 Vcc1 supply tuner 3 External RF AGC 4 N.C 5 SCL 6 SDA 7 N.C 8 N.C 9 N.C 10 N.C 11 GND 12 N.C 13 N.C 14 N.C 15 N.C 16 IF 1(N) 17 IF 1(P) 18 TH1 19 TH2 20 TH3 21 TH4 22 TU101 F86WT-2-E N/C 1 N/C 2 N/C 3 RF AGC 4 +B(5V) 5 SDA 6 SCL 7 N/C 8 N/C 9 AIF + 10 AIF - 11 TH1 12 TH2 13 TH3 14 TH4 15 TU102 NC\TDTK-G902D IFAGC_T 1 2 FB744 NC\120R/3000mA R1183 0R05 1/16W OSDA0 +B_5V R1185 0R05 1/16W G702D 2010.07.01 added NA Q1105 NC\PMBS3904 Near Tuner GND GND_A RFIN_CTL DTMB_DVBC_SW ATBM8848 C1140 10U 10V IF D+ATV , R1183 R1185 R1184 R1186 must connect BST_CTL# 12 BST_CTL# Ext. Demod. L1104 NC 0.22uH RF_AGC_S2T 1 2 FB745 NC\120R/3000mA TIF- RFAGC_I 2010.06.28 added L1105 0R05 1/10W T2S_TIF- 2010.06.23 added R1159 51R 1/16W 5% IFAGC_T IF BPF T2S_TIF- T2S_TIF+ TU_SCL R1176 0R05 1/4W T2D_TIF+ C1145 100N16V R1160 51R 1/16W 5% R1162 0R05 1/10W L1106 0R05 1/10W TIF+ T032D G702D Tuner R1181 NC\10K 1/16W 5% TU_5V_SCL + C1139 220UF 16V R1171 15 OHM +-5% 1/4W 5V_TUNER R1172 15 OHM +-5% 1/4W +12V VIN 3 VOUT 2 GND 1 U7007 +B_5V C1163 330NF 25V 5V_TUNER R1173 1K 1/10W 1% R1174 3K 1/10W 1% C1162 100N 16V C1141 100N 16V C1144 100N 16V 1 2 FB1102 120R/3000mA Vout=1.25(1+R1/R2) G9084TU3U TO-263T C1164 100N 50V R1175 15 OHM +-5% 1/4W 1 2 FB720 NC\120R/3000mA R1188 NC\0R05 1/16W T2S_TIF+ R1178 NC\4K7 1/16W 5% R1151 0R05 1/16W RF_AGC_CTL R1167 NC\10K 1/16W 5% R1168 NC\10K 1/16W 5% R1157 +B_5V R1169 NC\10K 1/16W 5% R1179 NC\4K7 1/16W 5% BPF_IF+ 1 2 3 Q1104 NC\PMBS3906 R1149 1K 1/16W 5% V3.3 38 DEMOD_TSDATA0 VDD33 ASIC_3V3 VDD12 IVINP TSSYNC TESTIO20 SDAS TS3 VDD33 VDD_DIV TS4 TS5 TU_SDA TU_SCL 30.4MHZ, using 27MHZ FP TS6 C1105 NC\100N16V TS7 TSCLK DEMOD_TSSYNC TSVALID IF_AGC_SW TESTIO20 C1138 NC\100N16V T2D_TIF+ T2D_TIF- TS1 Demod I2C REFCLK0 TS2 REFCLK1 VDD12 OSDA0 OSCL0 TS0 VDD33 VDD12 ASIC_3V3 VDD12 VDD33 C1134 NC\100N16V SDAS VDD_DIV IF_AGC_SW 9 IF_AGC_SW R1122 NC\10K 1/16W 5% IVINN R1124 NC\100K 1/16W TESTIO21 SCLM SDAM SDAM PWM0 TESTIO23 T2D_TIF- OEM MODEL Size Rev Date Sheet of TPV MODEL PCB NAME 称爹 T P V ( Top Victory Electronics Co . , Ltd. ) Key Component 絬 隔 瓜 絪 腹 M0B Custom 10 22 Monday , February 28, 2011 HW4 10. Demod (DTMB & DVB-T & PAL) T2D_TIF+ DEMOD_RESET DEMOD_TSVALID DEMOD_TSSYNC GPIOs from Demod IC TS6 DEMOD_TSDATA0 DEMOD_TSCLK Tuner I2C TS4 TS5 Serial TS TS3 TS2 TS0 TS1 Parallel TS RF_AGC_CTL SCLM TS7 C1110 NC\100N16V C1109 NC\100N16V DEMOD_RESET VDD33 TSBSYNC 1 TSBVLD 2 TSBCLK 3 TSB7 4 TSB6 5 VDD33 6 TSB5 7 TSB4 8 TSB3 9 VDD12 10 TSB2 11 TSB1 12 TSB0 13 PWM0 14 VDD12 15 CLK_REF_OUT 16 VDD_DIV 17 REFCLKI0 18 REFCLKI1 19 VDD_OSC 20 DVDD_ADC 21 ADVDD_ADC 22 QVINP 23 QVINN 24 IVINP 25 IVINN 26 AVDD_REF 27 REF_BIAS_EXT 28 VDD12 29 TESTIO16 30 TESTIO15 31 VDD33 32 TESTIO14 33 TESTIO13 34 TESTIO12 35 TESTIO11 36 TESTIO10 37 I2CINT 38 SCLM 39 SDAM 40 VDD12 41 SCLS 42 SDAS 43 DBGBUS17 44 VDD33 45 DBGBUS16 46 DBGBUS15 47 TESTIO17 48 TESTIO18 49 TESTIO19 50 VDD33 51 VDD12 52 DBGBUS14 53 DBGBUS13 54 NC 58 VDD12 57 NC 55 NC 56 VDD33 59 VDD33 60 DBGBUS12 61 DBGBUS11 62 VDD33 63 DBGBUS10 64 VDD33 65 PWM1 66 VDD33 67 VDD12 68 RESETN 69 TEST0 71 TEST1 72 DBGSEL 70 GND 73 U101 NC\ATBM8848 TP04 1 2 X1101 NC\27MHZ V3.3 AVDD3V3 PWM0 C1112 NC\100N16V C1111 NC\100N16V 1 2 LED1101 NC\LED C1114 NC\100N16V C1113 NC\100N16V C1116 NC\100N16V C1115 NC\100N16V VDD33 TP05 R1119 NC\10K +-1% 1/16W TESTIO23 C1117 NC\100N16V C1118 NC\100N16V TP08 1 2 3 4 8 7 6 5 RP1101 NC\22oHM 1/16W TP26 + C1101 NC\220UF 16V TU_SDA DEMOD_TSVALID C1129 NC\18pF 50V R1101 NC\1M 1/16W TP03 R1112 NC\0R05 1/16W L1101 NC\2.2uH C1128 NC\18pF 50V TP02 C1107 NC\100N16V R1118 NC\10K +-1% 1/16W DEMOD_TSCLK TP06 TP01 TP07 1 2 FB1111 NC\120R/3000mA R1103 NC\100K 1/16W C1130 NC\1uF 16V ASIC_3V3 VDD33 VDD12 V3.3 AVDD1V2 V1.2 AVDD3V3 ASIC_3V3 VDD33 V3.3 DEMOD_RESET 12 V3.3 DEMOD_TSDATA0 12 DEMOD_TSCLK 12 DEMOD_TSVALID 12 DEMOD_TSSYNC 12 TU_SCL 9 OSCL0 8,9,12,13,18,20 OSDA0 8,9,12,13,18,20 T2D_TIF+ 9 T2D_TIF- 9 TU_SDA 9 IF_AGC_D2T 9 GND 4,5,6,7,8,9,11,12,13,14,15,16,17,18,19,20,21,22 TESTIO21 C1106 NC\100N16V REFCLK1 1 2 FB1110 NC\120R/3000mA DTMB_RESETN IVINP 1 2 FB1112 NC\120R/3000mA R1117 NC\0R05 1/16W C1135 NC\5PF 50V TSCLK Near to ALBM8848 TESTIO21 56k~59k 5% C1136 NC\5PF 50V R1113 NC\0R05 1/16W TESTIO24 R1115 NC\2.7K 1/16W 1% + C1119 NC\220UF 16V C1127 NC\1uF 16V R1125 NC\330R 1/16W 5% TS0 IF_AGC_D2T R1114 NC\2.7K 1/16W 1% ASIC_3V3 close to ATBM8848 R1102 NC\56K 1% TESTIO25 1 2 FB1109 NC\120R/3000mA TESTIO24 TESTIO27 TESTIO26 TESTIO25 REFCLK0 R1120 NC\4.7K 1% SCLS R1116 NC\0R05 1/16W R1104 NC\100K 1/16W + C1108 NC\220UF 16V C1133 NC\100N16V TSSYNC LOCK IVINN R1105 NC\100K 1/16W OSCL0 OSDA0 TU_SCL DTMB_RESETN TESTIO26 R1121 NC\4.7K 1% SuNing C1120 NC\100N16V C1121 NC\100N16V C1122 NC\100N16V C1123 NC\100N16V C1124 NC\100N16V C1125 NC\100N16V R1106 NC\100K 1/16W C1102 NC\1uF 16V R1107 NC\100K 1/16W C1137 NC\100N16V R1126 NC\200R 1/16W 5% TESTIO27 C1103 NC\1uF 16V C1126 NC\100N16V TSVALID 1 2 FB1108 120R/3000mA R1108 NC\100K 1/16W RF_AGC_CTL 9 RF_AGC_CTL R1127 NC\10K 1/16W 5% ASIC_3V3 VDD33 VDD33 VDD33 1 2 FB1107 120R/3000mA TESTIO22 SCLS VDD33 VDD12 IF_AGC_D2T VDD33 VDD12 VDD33 C1104 NC\1uF 16V VDD12 R1109 NC\100K 1/16W R1123 NC\0R05 1/16W TESTIO22 39 C308 100N 16V 1 2 t TH301 8V 0R4 OEM MODEL Size Rev Date Sheet of TPV MODEL PCB NAME 称爹 T P V ( Top Victory Electronics Co . , Ltd. ) Key Component 絬 隔 瓜 絪 腹 M0B B 11 22 Monday , February 28, 2011 HW4 11. USB1 & USB2 C304 NC\4P7 50V USB_PWR_OCP0 R309 NC\15K 1/16W 5% 1 2 FB307 NC\120R/3000mA VUSB_5V 5V_USB GND 4,5,6,7,8,9,10,12,13,14,15,16,17,18,19,20,21,22 VUSB_5V 5V_SW R307 0R05 1/16W USB_DP1 12 USB_DM1 12 USB_PWR_OCP0 12 USB_DP0 12 USB_DM0 12 USB_PWR_OCP1 12 USB_DP0 USB_DM0 EQUAL LENGTH & DIFFERENTIAL IMPEDANCE 90 Ohm USB1_D+ USB1 VUSB_5V R308 0R05 1/16W USB_DP1 USB_DM1 EQUAL LENGTH & DIFFERENTIAL IMPEDANCE 90 Ohm + C302 100uF/16V 1 2 3 4 5 6 7 8 1 2 3 4 CN104 USB CONN R317 0R05 1/16W + C306 100uF/16V 1 2 t TH302 8V 0R4 USB2_D+ USB_DM1 USB_DP1 USB_DM0 USB_DP0 R310 NC\15K 1/16W 5% R318 0R05 1/16W H: OK L: O.C. R319 NC\15K 1/16W 5% R320 NC\15K 1/16W 5% 3 1 2 D302 NC\BAV99 USB_PWR_OCP1 R311 47K R306 22K 3 1 2 D301 NC\BAV99 3 1 2 D304 NC\BAV99 3 1 2 D303 NC\BAV99 H: OK L: O.C. R304 22K USB2 USB2_D- R305 47K C305 NC\4P7 50V USB_PWR_OCP0 USB_PWR_OCP1 C309 NC\4P7 50V C310 NC\4P7 50V C311 10U 16V 1 2 3 4 5 7 8 6 CN103 USB CONN 5VESD C303 100N 16V USB1_D- 40 HDMI_S1 L JTRST# 15 JTDI 15 JTMS 15 JTCK 15 VGA_SDA IF_AGC_S2T 9 RF_AGC_S2T 9 BL_DIM_PWM 4 PACLE 13 PAALE 13 POWE# 13 MONITOR_OUT AV3 PDD5 13 PARB# 13 POCE1# 13 PDD2 13 PDD3 13 PDD4 13 POOE# 13 POCE0# 13 PDD0 13 PDD1 13 SPDIF_OUT 8,17 PDD6 13 PDD7 13 KEY2 GND 4,5,6,7,8,9,10,11,13,14,15,16,17,18,19,20,21,22 AOSDATA1 13 AIN0_R_AADC AIN0_L_AADC OIRI OPWRSB LED_RED_OFF# USB_DP1 11 USB_DM1 11 ADC_KEY OXTALI 13 USB_DP0 11 USB_DM0 11 ORESET# 13 U0TX 15 U0RX 15 OXTALO 13 LED_RED_OFF# 16 OSCL0 8,9,10,13,18,20 OSDA0 8,9,10,13,18,20 R412 1.3K 1% OIRI 16 OPWRSB 5 HDMI_S1 AIN0_R_AADC 7 AIN0_L_AADC 7 ADC_KEY 16 HP_DET# 18 LVDS_PWR_EN 5 USB_PWR_OCP1 11 USB_PWR_OCP0 11 DDC_WP# 6,8 STANDBY 4,18 BL_ON/OFF# 4 AIN_CTL1 7 MUTE_CTL 18 PWR_OK 4 AIN_CTL0 7 MEMORY_WP# 13 DTMB_DVBC_SW 9 OPCTRL4 13 SPK_MUTE 18 LIT_SENSOR 16 Analog Normal Power C412 10U 10V DRAM IO Power (Close to SoC) VCCK BP RP VSYNC HSYNC GP SOG VGA_SDA VGA_SCL VGACOM AVDD33_DAC MJC_RST 20 MJC_RST AVDD33_LVDSTX VCCK AV1 AV2 USB_PWR_OCP0 BL_ON/OFF# AL1O TP37 SPDIF_OUT OPCTRL5 13 PDD2 PDD0 IF_AGC RF_AGC DVDD3V3 OPCTRL5 PDD1 PDD7 PDD6 PDD4 PDD3 DVDD3V3 DVDD3V3 PDD5 DEMOD_TSDATA0 DEMOD_TSCLK DEMOD_TSVALID DEMOD_TSSYNC AVDD33_IFPGA AVDD33_DEMOD T2S_TIF+ Normal GPIO ADC-in & GPIO AADC STBY GPIO DDRV AVDD33_CVBS AV1_CVBS CVBS_COM AVDD12_DEMOD R405 0R05 1/16W VCCK VCCK PWR_OK SPK_MUTE GPIO_6 E-Fuse A_Reset DTMB_DVBC_SW MUTE_CTL LVDS_PWR_EN BL_ON/OFF# HP_DET# DEMOD_TSDATA0 DEMOD_TSSYNC DEMOD_TSVALID USB_PWR_OCP0 DDC_WP# USB_PWR_OCP1 DEMOD_TSCLK ORESET# PAALE PACLE OSCL0 OSDA0 U0TX U0RX Demod TS POCE0# POWE# POOE# PARB# POCE1# AOSDATA1 OIRI OPWRSB BL_DIM_PWM TP35 HDMI_S2 PWR5V_B PWR5V_C HDMI_S1 SPDIF_OUT DEMOD_RESET AVDD33_PDM_STB Standby Power PWR_OK LED_WGB PWR5V_A AIN_CTL1 TP38 AOMCLK AVDD33_PDM_STB VGA R487 4K3 1/16W 5% RF_AGC_S2T C401 47nF 16V R429 10K 1/16W 5% HDMI PWR5V_A 5V_SW HDMI_SDA HDMI_SCL HDMI_HPD1 HDMI_CEC M_RX1_C M_RX1_1B AVDD33_USB_2P Q402 NC\PMBS3904 AV2_CVBS M_RX1_1 M_RX1_0B M_RX1_0 M_RX1_CB R403 1K 1/16W 5% RF_AGC M_RX1_2B M_RX1_2 C413 10U 10V VCCK HDMI_S2 TP28 ADAC AR1O AL1O OPCTRL4 VCCK C403 1uF 16V BST_CTL# I2S AOLRCK AOBCLK AOMCLK AOSDATA0 DVDD3V3 VCCK Strapping & GPIO R411 10K 1/16W 5% LVDS 3.3V IO Power (Close to So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lose to MT5301 AR1O AVDD33_AADC AVDD33_DAC TP32 ARC_ON USB1 & 2 AVDD33_LVDSTX R454 0R05 1/16W AV2_CVBS AV2_CVBS 7 AVDD33_XTAL_STB Core Power (Close to SoC) AVDD33_REG_STB LED_RED_OFF# VCCK POCE0# PDD7 PDD6 POOE# NOR IF_AGC_S2T T2S_TIF- BST_CTL# 9 BST_CTL# TP33 ARC_ON 8 ARC_ON MONITOR_OUT PR1P COM1 Y1P SOY1 AVDD12_RGB AVDD33_VDAC VDAC_FS PB1P GP HSYNC VSYNC RP BP VGACOM SOG OSCL0 OSDA0 VGA_SDA VGA_SCL STANDBY OXTALI OXTALO System IO U0RX U0TX ORESET# 1_A11 1_A9 1_A12 1_A10 1_A13 SY1 SC1 RDQ1 RDQS1 RDQS0 RDQS0# RDQS1# RDQ0 RDQ5 RDQ6 RDQ7 RDQ3 RDQ2 RDQ13 RDQ9 RDQ14 RDQ15 RDQ4 RDQM1 RDQ10 RDQ11 RDQ12 RDQ8 1_A2 RDQM0 1_CS# 1_RAS# 1_CKE 1_BA0 1_BA2 1_A0 1_WE# 1_ODT 1_CAS# 1_A1 1_BA1 1_A3 1_A4 1_A5 1_A6 1_A7 1_A8 AIN_CTL1 3V3SB TP39 DDR2 DDC_WP# IF_AGC AVDD33_HDMI OPWM0_100HZ AVDD33_AADC MEMORY_WP# USB_DP0 USB_DM0 USB_VRT USB_DP1 USB_DM1 PACLE POWE# PARB# POCE1# PAALE PDD1 PDD4 PDD3 PDD2 PDD0 PDD5 DEMOD_RESET NAND MJC_RST BL_DIM_PWM LVDS_PWR_EN LIT_SENSOR OEM MODEL Size Rev Date Sheet of TPV MODEL PCB NAME 称爹 T P V ( Top Victory Electronics Co . , Ltd. ) Key Component 絬 隔 瓜 絪 腹 M0B Custom 12 22 Monday , February 28, 2011 HW4 12. MT5310 QFP256 AV1_CVBS CVBS_COM VMID_AADC C441 10U 10V TP40 A_Reset A_Reset 18 AVDD33_XTAL_STB AVDD12_PLL C436 100N16V R449 0R05 1/16W JTMS JTDO JTDI JTCK OXTALO AVDD33_REG_STB OXTALI LIT_SENSOR DTMB_DVBC_SW FSRC_WR 1 VCC3IO 3 GPIO14 2 AVDD12_VPLL 4 AE5P 5 AE5N 6 AE4P 7 AE4N 8 AE3P 9 AE3N 10 AECKP 11 AECKN 12 AE2P 13 AE2N 14 AE1P 15 AE1N 16 AE0P 17 AE0N 18 AVDD33_LVDSA 19 AVDD33_LVDSA 20 AO5P 21 AO5N 22 AO4P 23 AO4N 24 AO3P 25 AO3N 26 AOCKP 27 AOCKN 28 AO2P 29 AO2N 30 AO1P 31 AO1N 32 AO0P 33 AO0N 34 VCCK 35 VCCK 36 VCCK 37 AVDD12_MEMPLL 38 AVSS12_MEMPLL 39 RODT//RCKE 40 RA8//RA10 41 RA13//RBA1 42 RA11//RA4 43 RA4//RA1 44 RA6//RA6 45 RA0//RA8 46 RA2//RA11 47 RCAS_//RA12 48 RCS_//RRAS_ 49 RRAS_//RCAS_ 50 RA9//RWE_ 51 VCC2IO 52 RA12//RA0 53 RA7//RA13 54 RA5//RA9 55 NC//RRESET_ 56 RA3//RA7 57 RA1//RA2 58 RA10//RA5 59 RBA1//RA3 60 RBA0//RBA2 61 RBA2//RBA0 62 RWE_//RCS_ 63 RCKE//RODT 64 AVDD33_XTAL_STB 192 XTALI 191 XTALO 190 AVDD33_DEMOD 189 AVSS33_DEMOD 188 AVSS12_DEMOD 187 AVDD33_IFPGA 186 ADCINN_DEMOD 185 ADCINP_DEMOD 184 AVDD12_DEMOD 183 AVDD33_CVBS 182 CVBS0P 181 CVBS_COM 180 CVBS1P 179 SY0 178 SC0 177 SY1 176 SC1 175 AVDD12_PLL 174 VCCK 173 FS_VDAC 172 AVDD33_VDAC 171 VDAC_OUT1 170 VDAC_OUT2 169 AVSS12_RGB 168 AVDD12_RGB 167 PR0P 166 PB0P 165 COM0 164 Y0P 163 SOY0 162 PR1P 161 PB1P 160 COM1 159 Y1P 158 SOY1 157 RP 156 COM 155 GP 154 SOG 153 BP 152 HSYNC 151 VSYNC 150 AVDD33_VGA_STB 149 AVDD10_LDO 148 ADIN4_SRV 147 ADIN3_SRV 146 ADIN2_SRV 145 ADIN1_SRV 144 ADIN0_SRV 143 VCCK 142 VGA_SCL 141 VGA_SDA 140 OPWRSB 139 OPCTRL1 138 OPCTRL0 137 OIRI 136 U0TX 135 U0RX 134 AVDD33_PDM_STB 133 OPCTRL2 132 OPCTRL4 131 OPCTRL3 130 OPCTRL5 129 GPIO4 256 GPIO8 255 GPIO7 254 GPIO12 253 GPIO6 252 GPIO11 251 GPIO3 250 GPIO10 249 GPIO2 248 GPIO1 247 GPIO0 246 VCC3IO 245 VCCK 244 GPIO13 243 POWE_ 242 PAALE 241 PACLE 240 POCE1_ 239 PARB_ 238 POOE_ 237 POCE0_ 236 PDD7 235 VCC3IO 234 PDD6 233 PDD5 232 PDD4 231 PDD3 230 PDD2 229 PDD1 228 PDD0 227 CI_INT 226 SPI_CLE 225 SPI_DATA 224 SPI_CLK 223 VCCK 222 VCC3IO 221 DEMOD_TSDATA0 220 DEMOD_TSSYNC 219 DEMOD_TSVAL 218 DEMOD_TSCLK 217 OSDA2 216 OSCL2 215 DEMOD_RST 214 RF_AGC 213 IF_AGC 212 AOLRCK 211 AOSDATA0 210 AOMCLK 209 AOBCK 208 AOSDATA1 207 ASPDIF 206 VCCK 205 VCCK 204 AR1_ADAC 203 AR0_ADAC 202 AL1_ADAC 201 AL0_ADAC 200 AVSS33_DAC 199 AVDD33_DAC 198 AVDD33_AADC 197 AIN0_L_AADC 196 VMID_AADC 195 AIN0_R_AADC 194 LOUTP 193 VCCK 65 RVREF 66 RDQ4//RDQ4 67 RDQ3//RDQ6 68 VCC2IO 69 RDQ1//RDQ2 70 RDQ6//RDQ0 71 RDQ12//RDQ11 72 RDQ9//RDQ9 73 VCC2IO 74 RDQ14//RDQ13 75 RDQ11//RDQ15 76 RDQM1//RDQM1 77 VCCK 78 RDQS0//RDQS0 79 RDQS0_//RDQS0_ 80 RDQM0//RDQM0 81 VCC2IO 82 RDQS1//RDQS1 83 RDQS1_//RDQS1_ 84 RDQ15//RDQ12 85 RDQ8//RDQ14 86 VCC2IO 87 RDQ10//RDQ10 88 RDQ13//RDQ8 89 RDQ7//RDQ1 90 RDQ0//RDQ3 91 VCC2IO 92 RDQ2//RDQ7 93 RDQ5//RDQ5 94 VCC2IO 95 RCLK0//RCLK0 96 RCLK0_//RCLK0_ 97 VCCK 98 JTDO 99 JTCK 100 JTMS 101 JTDI 102 JTRST_ 103 OPWM0 104 VCC3IO 105 VCCK 106 USB_2P_DM1 107 USB_2P_DP1 108 USB_2P_DM0 109 USB_2P_DP0 110 AVDD33_USB_2P 111 USB_2P_VRT 112 AVDD33_HDMI 113 RX_CB 114 RX_C 115 RX_0B 116 RX_0 117 RX_1B 118 RX_1 119 RX_2B 120 RX_2 121 AVDD12_HDMI 122 HDMI_CEC 123 HDMI_SDA 124 HDMI_SCL 125 HDMI_HPD 126 PWR5V 127 ORESET_ 128 EPAD_GND 257 MT5301B U401 R413 0R05 1/16W C414 100N16V C450 100N16V C428 0.1uF 16V TP22 C445 100N16V R446 0R05 1/16W R410 5.1K 1% C411 100N16V C426 0.1uF 16V C438 100N16V C410 100N16V AVDD12_MEMPLL C422 100N16V R418 0R05 1/16W RVREF5 R419 0R05 1/16W C447 100N16V C409 100N16V AOUT_EN 17 R436 0R05 1/16W C433 100N16V C421 100N16V C404 100N16V C440 100N16V R404 10K 1/16W 5% C408 100N16V TP41 R447 0R05 1/16W R450 0R05 1/16W C435 100N16V C449 100N16V R420 0R05 1/16W R406 4K7 1/16W 5% C407 100N16V R448 0R05 1/16W R415 0R05 1/16W C429 0.1uF 16V TP24 C444 100N16V R407 1K 1/16W 1% + C419 100uF/16V AIN0_R_AADC AIN0_L_AADC C405 100N16V R423 100R 1/16W 5% DDRV C437 100N16V DDRV DDRV DDRV DDRV DDRV R421 0R05 1/16W RDQM1 RDQS1 RDQS0 RDQS0# RDQS1# TP23 RDQ0 RDQ1 RDQ7 RCLK0# RCLK0 RDQM0 C418 100N16V R445 0R05 1/16W RDQ11 RDQ6 RDQ5 RDQ3 RDQ2 C430 0.1uF 16V C406 100N16V RDQ13 RDQ14 RDQ4 RDQ9 RDQ8 C451 100N16V R408 1K 1/16W 1% STANDBY VCCK RDQ10 RDQ12 RDQ15 R409 10K 1/16W 5% C446 100N16V C425 100N16V C439 100N16V C417 100N16V R401 0R05 1/16W R422 0R05 1/16W R417 0R05 1/16W R416 0R05 1/16W C431 4.7UF 16V R453 0R05 1/16W C424 100N16V R486 560R 1% C432 100N16V C416 100N16V C402 47nF 16V OPWRSB C448 100N16V C434 100N16V R424 100R 1/16W 5% R444 47 OHM 1/16W R488 0R05 1/16W R414 0R05 1/16W C415 100N16V R451 0R05 1/16W Tuner-DIF T2S_TIF- T2S_TIF+ C423 100N16V OPWM0_100HZ C442 100N16V C427 0.1uF 16V OPCTRL5 DDRV 3V3SB VCCK DDRV 3V3SB DVDD3V3 DVDD3V3 AVDD1V2 AVDD3V3 AVDD3V3 AVDD3V3 AVDD3V3 AVDD1V2 AVDD1V2 AVDD1V2 AVDD1V2 AVDD3V3 AIN_CTL0 AVDD3V3 AVDD1V2 AVDD3V3 AVDD3V3 ADAC_PWR 3V3SB GP 6 RP 6 VSYNC 6 HSYNC 6 BP 6 VGACOM 6 SOG 6 VGA_SCL VGA_SDA RDQ0 14 CVBS_COM 7 AV1_CVBS 7 RDQ3 14 RDQ2 14 RDQ1 14 RF_AGC_S2T RDQ7 14 RDQ6 14 RDQ5 14 RDQ4 14 RDQ10 14 RDQ9 14 RDQ8 14 RDQ13 14 RDQ12 14 RDQ11 14 1_A0 14 RDQ15 14 RDQ14 14 1_A3 14 1_A2 14 1_A1 14 1_A7 14 1_A6 14 1_A5 14 1_A4 14 1_A10 14 1_A9 14 1_A8 14 1_A13 14 1_A12 14 1_A11 14 1_BA2 14 1_BA1 14 1_BA0 14 1_WE# 14 RCLK0# 14 RCLK0 14 1_CKE 14 1_RAS# 14 1_CAS# 14 1_ODT 14 RDQS1# 14 RDQS1 14 1_CS# 14 RDQM1 14 RDQS0# 14 RDQS0 14 CVI1 DEMOD_TSVALID 10 DEMOD_TSCLK 10 RDQM0 14 PB1P Y1P SOY1 PR1P COM1 DEMOD_RESET 10 DEMOD_TSDATA0 10 DEMOD_TSSYNC 10 R402 NC\10K 1/16W 5% TX_AE0N 15 TX_AECKN 15 TX_AO3N 15 TX_AO2P 15 TX_AE1N 15 TX_AO0P 15 TX_AE4P 15 TX_AE0P 15 TX_AECKP 15 TX_AO1N 15 TX_AO4N 15 TX_AOCKP 15 TX_AE3N 15 TX_AE2N 15 TX_AO3P 15 TX_AO1P 15 TX_AE1P 15 TX_AO2N 15 TX_AO4P 15 TX_AE3P 15 AOUTL 17 TX_AE4N 15 TX_AO0N 15 TX_AOCKN 15 PWR5V_C 8 PWR5V_B 8 TX_AE2P 15 T2S_TIF+ 9 HDMI_S2 8 HDMI_S1 8 Y1P 7 SOY1 7 T2S_TIF- 9 PB1P 7 COM1 7 PR1P 7 MONITOR_OUT 17 HDMI_SCL 8 HDMI_SDA 8 HDMI_CEC 8 M_RX1_CB 8 PWR5V_A 8 HDMI_HPD1 8 M_RX1_1B 8 M_RX1_0 8 M_RX1_0B 8 M_RX1_C 8 M_RX1_2 8 M_RX1_2B 8 M_RX1_1 8 AVDD12_VPLL VCCK AL1O 18 AR1O 18 AOSDATA0 H H H HDMI_S2 AOLRCK 18 AOSDATA0 18 VGA_SCL TP27 L HDMI C HDMI A L HDMI B JTDO 15 AOMCLK 18 AOBCLK 18 41 PDD3 12 Close to SoC OPCTRL5 R478 10K 1/16W 5% DVDD3V3 3V3SB OPCTRL4 Strapping 3V3SB AOSDATA1 PDD4 12 OPCTRL5 OPCTRL4 AOSDATA1 PDD5 12 R480 NC\1M 1/16W STBC CRYSTAL C458 27PF 50V OXTALI OXTALO DVDD3V3 MEMORY_WP# 12 PDD6 12 C460 100N 16V C457 27PF 50V 1 2 3 4 5 6 CN402 CONN PDD7 12 DVDD3V3 R471 NC 6K8 1/10W 1% Reset IC 5VSB GND 1 RESET 2 VCC 3 U406 MAX809STRG R470 NC 1K 1/10W 1% R468 100K 1/16W 1 2 3 4 X401 27MHz R467 NC\5K1 1/16W 5% PDD7 PDD6 R472 4K7 1/16W 5% PDD5 PACLE NC23 39 NC1 1 NC2 2 NC3 3 NC4 4 NC5 5 NC26 46 ALE 17 CLE 16 WE 18 NC17 26 NC8 11 WP 19 RY/BY1 7 NC9 14 NC10 15 NC18 27 NC19 28 NC11 20 NC12 21 NC13 22 I/O3 32 NC20 33 VSS2 36 VCC1 12 RE 8 VCC2 37 I/O2 31 I/O1 30 I/O0 29 VSS1 13 NC25 45 I/O7 44 I/O6 43 I/O5 42 I/O4 41 NC24 40 NC14 23 NC15 24 NC16 25 CE1 9 NC21 34 NC22 35 NC27 47 PRE 38 NC6 6 NC7 10 NC28 48 U403 HY27US08561A-TPCB 256Mbit Nand Flash DVDD3V3 DVDD3V3 PAALE SMD/0402 SMD/0402 PDD4 POWE# PDD2 PARB# FLASH_WP# PDD3 PDD1 POOE# PDD0 3V3SB OSCL0 OSDA0 OPCTRL4 12 R457 NC\0R05 1/16W R469 0R05 1/16W Q401 PMBS3904 R476 NC\10K 1/16W 5% DVDD3V3 C456 100N 16V R458 NC\10K 1/16W DVDD3V3 R462 4.7K 1% R474 NC\10K 1/16W 5% C455 NC\100N 16V OPCTRL5 12 3V3SB R463 4.7K 1% R479 NC\10K 1/16W 5% R456 4K7 1/16W 5% R477 10K 1/16W 5% AOSDATA1 12 R475 10K 1/16W 5% 5VSB R459 NC\4K7 1/16W 5% C462 10U 10V R465 10K 1/16W 5% H : Write Protect L : Write Enable MEMORY_WP# R455 NC\4K7 1/16W 5% OSCL0 8,9,10,12,18,20 OSDA0 8,9,10,12,18,20 ORESET# NVRAM VSS 4 VCC 8 SDA 5 SCL 6 E0 1 E1 2 E2 3 WC 7 U405 CAT24C128YI R464 2.2K 1/16W C454 220N16V I2C address at A0 OSCL0 PAALE 12 POCE0# 12 POWE# 12 MEMORY_WP# PACLE 12 GND 4,5,6,7,8,9,10,11,12,14,15,16,17,18,19,20,21,22 PARB# 12 POOE# 12 POCE1# 12 POCE1# C452 NC\10U 10V C461 100N 16V R461 10K 1/16W 5% OXTALI 12 OXTALO 12 OXTALO ORESET# OXTALI POOE# PARB# POCE1# PAALE PACLE PDD4 PDD3 PDD2 PDD0 POWE# POCE0# PDD5 PDD1 PDD7 PDD6 R460 NC\4K7 1/16W 5% ORESET# 12 PDD0 12 R473 4K7 1/16W 5% PDD1 12 PDD6 NOR Flash CS# 1 SO/SIO1 2 WP#/SIO2 3 GND 4 SI/SIO0 5 SCLK 6 NC/SIO3 7 VCC 8 U404 NC\MX25L6445EM2I-10G C453 NC\100N 16V DVDD3V3 OSDA0 PDD7 POCE0# POOE# OEM MODEL Size Rev Date Sheet of TPV MODEL PCB NAME 称爹 T P V ( Top Victory Electronics Co . , Ltd. ) Key Component 絬 隔 瓜 絪 腹 M0B C 13 22 Monday , February 28, 2011 HW4 13. SoC Peripheral PDD2 12 MEMORY_WP# H: Write L: Write Protect FLASH_WP# 42 J1 RVREF1 DDRV A1 B_A3 B_A1 B_A4 B_A6 B_A7 B_A5 B_A2 B_A12 B_A13 B_A8 B_A10 B_A11 B_A9 B_A0 E1 R1 E9 G7 G9 1_A7 1_A9 1_A12 1_A5 A9 C7 C9 B_CAS# B_WE# CLK0# CLK0 B_RAS# B_ODT B_CS# B_BA2 B_BA0 B_BA1 VDD A1 NC A2 VSS A3 VSSQ A7 UDQS A8 VDDQ A9 DQ14 B1 VSSQ B2 UDM B3 UDQS B7 VSSQ B8 DQ15 B9 VDDQ C1 DQ9 C2 VDDQ C3 VDDQ C7 DQ8 C8 VDDQ C9 DQ12 D1 VSSQ D2 DQ11 D3 DQ10 D7 VSSQ D8 DQ13 D9 VDD E1 NC E2 VSS E3 VSSQ E7 LDQS E8 VDDQ E9 DQ6 F1 VSSQ F2 LDM F3 LDQS F7 VSSQ F8 DQ7 F9 VDDQ G1 DQ1 G2 VDDQ G7 DQ0 G8 VDDQ G9 DQ4 H1 VSSQ H2 DQ3 H3 DQ2 H7 VSSQ H8 DQ5 H9 VDDL J1 VREF J2 VSS J3 VSSDL J7 CK J8 VDD J9 CKE K2 WE K3 RAS K7 CK K8 ODT K9 BA2 L1 BA0 L2 BA1 L3 CAS L7 CS L8 A10/AP M2 A1 M3 A2 M7 A0 M8 VDD M9 VSS N1 A3 N2 A5 N3 A6 N7 A4 N8 A7 P2 A9 P3 A11 P7 A8 P8 VSS P9 VDD R1 A12 R2 NC R3 NC R7 NC R8 VDDQ G3 U402 W971GG6JB-18 G1 G3 C1 C3 J9 M9 Damping for DDR2#1 ADDR/CMD B_A8 B_CKE RDQ2 12 1_A7 12 1_A8 12 1_A11 1_A9 1_A12 1_A10 RDQ3 12 1_A13 RDQ4 12 1_A9 12 B_A7 B_A10 B_A9 GND 4,5,6,7,8,9,10,11,12,13,15,16,17,18,19,20,21,22 B_A4 B_A6 B_A5 B_BA1 B_BA0 B_A13 B_A0 B_A11 B_A3 B_ODT B_A2 B_CAS# B_A12 B_BA2 B_A1 B_WE# RDQ5 12 1_A10 12 B_CKE B_RAS# B_CS# RDQ6 12 1_A11 12 C465 100N16V RDQ7 12 RDQ8 12 1_A13 12 1_WE# 12 1_A0 12 1_CAS# 12 1_A12 12 RDQ9 12 1_ODT 12 1_BA1 12 1_RAS# 12 RDQ10 12 CLK0 CLK0# RCLK0 RCLK0# Close to MT5310 Close to DDR2 Damping & Termination for CLK C466 100N16V RDQ11 12 RDQ1 RDQS1 RDQS0 RDQS0# RDQS1# RDQ5 RDQ6 RDQ7 RDQ3 RDQ2 RDQ9 RDQ14 RDQ15 RDQ4 RDQ0 RDQ11 RDQ12 RDQ8 RDQ13 RCLK0# RCLK0 RDQ12 12 RDQM0 RDQM1 RDQ10 RDQ14 12 RDQ13 12 1_A2 12 RDQ15 12 1_A1 12 1_A2 1_CKE 1_BA0 1_BA2 1_A0 1_CS# 1_ODT 1_CAS# 1_A1 1_BA1 1_RAS# 1_A3 12 RCLK0# 12 RCLK0 12 1_WE# RDQS1# 12 1_CS# 12 RDQS1 12 RDQS0 12 1_A4 12 1_A3 1_A4 1_BA0 12 RDQS0# 12 1_CKE 12 RDQ0 12 RDQM1 12 1_A5 12 1_BA2 12 C467 100N16V RDQM0 12 1_A7 1_A8 1_A5 1_A6 RDQ1 12 1_A6 12 C468 100N16V DDRV CAPs Close to DDR2#1 DDRV C469 100N16V OEM MODEL Size Rev Date Sheet of TPV MODEL PCB NAME 称爹 T P V ( Top Victory Electronics Co . , Ltd. ) Key Component 絬 隔 瓜 絪 腹 M0B B 14 22 Monday , February 28, 2011 HW4 14. DDR2 C464 100N16V C470 100N16V RDQ3 RDQ2 RDQ1 RDQ4 RDQ0 RDQ5 RDQ6 RDQ7 RDQ12 RDQ8 RDQ13 RDQ9 RDQ14 RDQ15 RDQ10 RDQ11 DDR2#1-64Mx16-1066MHz C471 100N16V 1_A13 1_ODT 1_A8 C472 100N16V RDQS1 RDQS1# 1_BA2 1_WE# 1_CKE 1_BA0 R484 1.1KOHM +-1% 1/10W 1_A3 1_A10 1_BA1 1_A1 1_A0 1_A4 1_A11 1_A6 C463 100N16V RDQS0# RDQS0 1 2 3 4 8 7 6 5 RP402 100 OHM 1/16W 1 2 3 4 8 7 6 5 RP403 100 OHM 1/16W RDQM0 RDQM1 1 2 3 4 8 7 6 5 RP404 100 OHM 1/16W R481 0R05 1/16W 1 2 3 4 8 7 6 5 RP401 100 OHM 1/16W 1 2 3 4 8 7 6 5 RP405 100 OHM 1/16W R482 0R05 1/16W 1_RAS# 1_A2 1_CAS# 1_CS# 1 2 3 4 8 7 6 5 RP406 100 OHM 1/16W DDRV R483 100R 1/16W 5% R485 1.1KOHM +-1% 1/10W 43 OEM MODEL Size Rev Date Sheet of TPV MODEL PCB NAME 称爹 T P V ( Top Victory Electronics Co . , Ltd. ) Key Component 絬 隔 瓜 絪 腹 M0B Custom 15 22 Monday , February 28, 2011 HW4 15. LVDS & JTAG & UART 1 2 3 4 5 6 7 8 9 10 11 CN415 NC CONN R198 NC 0R05 1/16W R195 NC 0R05 1/16W R196 NC 0R05 1/16W FHD 8/10-Bit LVDS Connector >=26" TX_AE3P 12 TX_AE4N 12 TX_AE4P 12 TX_AE3N 12 TX_AO4P 12 TX_AO3N 12 TX_AO3P 12 TX_AO0P 12 TX_AO4N 12 TX_AO1N 12 TX_AO1P 12 TX_AO0N 12 TX_AOCKP 12 TX_AO2N 12 TX_AO2P 12 TX_AOCKN 12 TX_AE1P TX_AE1N TX_AO4N TX_AO4P TX_AE0P TX_AO3N TX_AO3P TX_AO1P TX_AO2N TX_AO2P TX_AOCKP TX_AOCKN TX_AE4P TX_AE0N TX_AO0N TX_AO0P TX_AO1N TX_AE2P TX_AECKN TX_AECKP TX_AE3N TX_AE3P TX_AE4N R197 NC 0R05 1/16W TX_AE2N TX_AE0P 12 TX_AE1P 12 TX_AE0N 12 TX_AE2N 12 TX_AE2P 12 TX_AE1N 12 TX_AECKN 12 TX_AECKP 12 1 2 3 CN410 CONN JTAG (ICE) Debug JTAG_DBGACK JTAG_DBGRQ 1 2 ZD137 NC\MLVG0402 1 2 ZD138 NC\MLVG0402 5VSB_2 C113 100N 50V N54124027 GND 4,5,6,7,8,9,10,11,12,13,14,16,17,18,19,20,21,22 U0TX U0RX 3V3SB 3V3SB UART Debug Tool (STBY) near CN101 R154 100R 1/16W 5% R156 100R 1/16W 5% R155 4K7 1/16W 5% R153 4K7 1/16W 5% C114 NC\10U 10V R143 0R05 1/16W OSCL0 8,9,10,12,13,18,20 OSDA0 OSCL0 OSDA0 8,9,10,12,13,18,20 Panel_12V_5V 1 2 FB105 120R/6000mA LVDSVDD DVDD3V3 TX_AOCKP TX_AOCKN TX_AO4P TX_AO2P TX_AE1P TX_AE2N TX_AE4N TX_AO1N TX_AO3N ODSEL TX_AO1P TX_AE3N TX_AE4P TX_AE2P TX_AO3P TX_AO0P TX_AE0N TX_AE0P TX_AE3P TX_AECKN TX_AECKP SELLVDS TX_AO0N TX_AO2N TX_AE1N TX_AO4N R142 NC\1K 1/16W 5% DVDD3V3 R141 NC\0R05 1/16W Close to IC MT5301B (U401) JTDO JTMS JTRST# JTCK JTDI R149 NC 1K 1/16W 5% R145 NC 10K 1/16W 5% R146 NC R150 NC 33R 1/16W 5% R144 NC 10K 1/16W 5% R152 NC 10K 1/16W 5% R147 NC 10K 1/16W 5% R151 NC 10K 1/16W 5% DVDD3V3 DVDD3V3 1 2 3 4 CN703 CONN 1 2 3 4 5 CN704 CONN RC_IR_5V JTDO 12 JTRST# 12 JTDI 12 JTMS 12 JTCK 12 JTMS JTDO JTDI JTCK JTRST# R233 NC\0R05 OHM 1 3 5 7 9 11 13 15 17 19 21 23 25 27 29 31 33 35 37 39 41 2 4 6 8 10 12 14 16 18 20 22 24 26 28 30 32 34 36 38 40 42 CN414 CONN near CN408 M_TX_AO4P M_TX_AO4N M_TX_AO3P M_TX_AO3N 1 2 3 4 8 7 6 5 RP104 0OHM 1/16W M_TX_AE4P 22 M_TX_AOCKP M_TX_AOCKN M_TX_AO2P M_TX_AO2N 1 2 3 4 8 7 6 5 RP105 0OHM 1/16W M_TX_AE4N 22 M_TX_AECKP 22 M_TX_AECKN 22 M_TX_AE3N 22 M_TX_AE3P 22 M_TX_AE1P 22 M_TX_AE2P 22 M_TX_AE2N 22 SuNing M_TX_AE1N 22 M_TX_AE0P 22 M_TX_AE0N 22 M_TX_AO1P M_TX_AO1N M_TX_AO0P M_TX_AO0N 1 2 3 4 8 7 6 5 RP106 0OHM 1/16W M_TX_AO3N 22 M_TX_AO4P 22 M_TX_AO4N 22 M_TX_AO3P 22 R140 1K 1/16W 5% M_TX_AO2N 22 M_TX_AOCKP 22 M_TX_AOCKN 22 M_TX_AO2P 22 M_TX_AO1N 22 M_TX_AO0P 22 M_TX_AE4P M_TX_AO0N 22 M_TX_AO1P 22 M_TX_AE3P M_TX_AE4N 1 2 3 4 8 7 6 5 RP101 0OHM 1/16W M_TX_AE3N M_TX_AECKP M_TX_AECKN M_TX_AE2P M_TX_AE2N 1 2 3 4 8 7 6 5 RP102 0OHM 1/16W TX_AO4P TX_AO4N TX_AO3P TX_AO3N TX_AOCKP TX_AOCKN TX_AO2P TX_AO1P TX_AO1N TX_AO0P TX_AO0N TX_AE4P TX_AE4N TX_AE3P TX_AE3N TX_AECKP TX_AECKN TX_AO2N TX_AE2P TX_AE2N TX_AE1P TX_AE1N TX_AE0P M_TX_AE1P M_TX_AE1N M_TX_AE0P M_TX_AE0N TX_AE0N 1 2 3 4 8 7 6 5 RP103 0OHM 1/16W TX_AE3N 12 TX_AE3P 12 TX_AO3P 12 TX_AE4N 12 TX_AE4P 12 TX_AO4N 12 TX_AO4P 12 TX_AO3N 12 TX_AO1P 12 TX_AO0N 12 TX_AO0P 12 TX_AOCKP 12 TX_AO2N 12 TX_AO2P 12 TX_AO1N 12 TX_AOCKN 12 BL_DIM_PWM TX_AE0P TX_AE1N TX_AE1P TX_AOCKN TX_AO3N TX_AO3P TX_AO4N TX_AO4P TX_AO1N TX_AO1P TX_AO2N TX_AO2P TX_AOCKP TX_AE3P TX_AE4N TX_AE4P TX_AE0N TX_AO0N TX_AO0P TX_AE2N TX_AE2P TX_AECKN TX_AECKP TX_AE3N TX_AE0P 12 TX_AE0N 12 TX_AE1P 12 TX_AECKP 12 TX_AE2N 12 TX_AE2P 12 TX_AE1N 12 TX_AECKN 12 TVTREF#1 R194 NC 0R05 1/16W U0TX 12 U0RX U0TX U0RX 12 44 LED_WGB KEY OEM MODEL Size Rev Date Sheet of TPV MODEL PCB NAME 称爹 T P V ( Top Victory Electronics Co . , Ltd. ) Key Component 絬 隔 瓜 絪 腹 M0B
