© 2006 松下电器产业株式会社版权所有。 未经本公司许可而复制或分发者均属违法。 ORDER NO. PPDS061234CC 高清晰等离子数字电视机 TH-42PV65C GPH9D 机型 技术规格 电源 交流 220 V,50/60Hz 耗电量 平均耗电量 365 W 待机耗电量 0.3 W 等离子显示屏 驱动方式 交流型 画面纵横比 16:9 对比度 最大 10,000:1 可见的屏幕尺寸 106 厘米 920 毫米 (W) × 518 毫米 (H) × 1,056 毫米 ( 对角线 ) 像素数 1,049,088(1,366(W) × 768(H))[4,098 × 768 点 ] 声音 喇叭 12 厘米 (W) × 6 厘米 (H) × 2 只，8Ω 音频输出 16 W(8 W+8 W),7%THD 耳机 M3 （3.5 毫米）插孔 × 1 PC 信号 VGA,SVGA, XGA SXGA…( 压缩 ) 水平扫描频率 31 - 69 kHz 垂直扫描频率 59 - 86 Hz 接收系统 / 频带名称 2 接收频道 （普通电视） 天线 - 背部 VHF/UHF 使用环境 温度：0°C - 40°C 湿度：20% - 80% RH( 非凝固状态 ) 连接端子 AV1 输入 音频 L- R RCA 针式 × 2 0.5 V[rms] 视频 RCA 针式 × 1 1.0 V[p-p](75Ω) S 视频 MINI DIN 4 针 Y:1.0 Vp-p(75Ω) C:0.286 V[p-p](75Ω) AV2 输入 音频 L- R RCA 针式 × 2 0.5 V[rms] 视频 RCA 针式 × 1 1.0 V[p-p](75Ω) 色差 Y P B / C B ,P R / C R 1.0 V[p-p]( 包括同步在内 ) ± 0.35 V[p-p] AV3 输入 音频 L- R RCA 针式 × 2 0.5 V[rms] 视频 RCA 针式 × 1 1.0 V[p-p](75Ω) 色差 Y P B / C B ,P R / C R 1.0 V[p-p]( 包括同步在内 ) ± 0.35 V[p-p] AV4 输入 音频 L- R RCA 针式 × 2 0.5 V[rms] 视频 RCA 针式 × 1 1.0 V[p-p](75Ω) S 视频 Mini DIN 4 针 Y:1.0 V[p-p](75Ω) C:0.286 V[p-p](75Ω) 其他 HDMI1/2 输入 A 型接头 PC 输入 高密度 D-SUB15 针 R,G,B /0.7V[p-p](75Ω) HD,VD/TTL 水平 2.0 - 5.0 V[p-p]( 高阻抗 ) 音频输入 RCA 针式 × 2 0.5 V[rms] 输出 音频 L- R RCA 针式 × 2 0.5 V[rms]( 高阻抗 ) 视频 RCA 针式 × 1 1.0 V[p-p](75Ω) 尺寸 (W × H × D) 1,020 毫米 × 704.5 毫米 × 95 毫米 重量 净重 30 公斤 执行标准 Q/YXNS3-2005 TH 彩色等离子电视机系列 注： • 设计和技术规格如有变更，恕不另行通知。文中出现的质量和尺寸均为近似值。 3 目录 页数 页数 1 可显示的输入信号--------------------------------- 5 2 安全警告----------------------------------------- 6 2.1. 一般准则 ----------------------------------- 6 3 静电敏感设备 (ES) 的静电放电保护 (ESD) ------------ 7 4 关于无铅焊接 (PbF) ------------------------------- 8 5 维修提示----------------------------------------- 9 6 等离子显示屏更换方式---------------------------- 10 6.1. 取下后盖 ---------------------------------- 10 6.2. 取下风扇 ---------------------------------- 10 6.3. 取下后端子盖 ------------------------------ 10 6.4. 取下 P 板 ---------------------------------- 10 6.5. 取下 PA 板 --------------------------------- 10 6.6. 取下调谐器单元 ---------------------------- 11 6.7. 取下 DG 板 --------------------------------- 11 6.8. 取下 TA 板 --------------------------------- 11 6.9. 取下 H 板 ---------------------------------- 11 6.10. 取下 HC 板 --------------------------------- 12 6.11. 取下 D 板 ---------------------------------- 12 6.12. 取下 SU 板 --------------------------------- 12 6.13. 取下 SD 板 --------------------------------- 12 6.14. 取下 SC 板 --------------------------------- 13 6.15. 取下 SS 板 --------------------------------- 13 6.16. 取下前支架 -------------------------------- 13 6.17. 取下 G 板和 GK 板 --------------------------- 13 6.18. 取下左右扬声器 ---------------------------- 14 6.19. 取下 S 板 ---------------------------------- 14 6.20. 取下 K 板 ---------------------------------- 14 6.21. 取下支撑架 -------------------------------- 14 6.22. 取下 C1 板 --------------------------------- 14 6.23. 取下 C2 板 --------------------------------- 14 6.24. 取下 AC 接入口 ----------------------------- 15 6.25. 从前面框 （玻璃）上取下等离子显示屏 ------- 15 6.26. 安装新的等离子显示屏 ---------------------- 15 7 导线布置---------------------------------------- 16 7.1. 导线 (1) ---------------------------------- 16 7.2. 导线 (2) ---------------------------------- 17 7.3. 导线 (3) ---------------------------------- 18 7.4. 导线 (4) ---------------------------------- 19 7.5. 导线 (5) ---------------------------------- 20 8 自检-------------------------------------------- 21 8.1. 发光二极管 LED 电源定时闪亮曲线图表 -------- 22 8.2. 无电源 ------------------------------------ 23 8.3. 无图像 ------------------------------------ 24 8.4. 显示屏局部故障 ---------------------------- 25 9 维修模式功能------------------------------------ 26 9.1. 如何进入维修模式 1 ------------------------ 26 9.2. 如何进入维修模式 2 ------------------------ 26 9.3. 选项说明 ---------------------------------- 28 10 调整步骤---------------------------------------- 30 10.1. 驱动器设置 -------------------------------- 30 10.2. 初始化脉冲调整 ---------------------------- 31 10.3. P.C.B. （印刷电路版）更换 ----------------- 31 10.4. 调整点位置 -------------------------------- 32 10.5. 测试点位置---------------------------------32 11 微调 --------------------------------------------33 11.1. PAL 显示屏白平衡调整 -----------------------33 11.2. HD 白平衡调整 ------------------------------34 11.3. 副亮度调整---------------------------------35 11.4. ABL 调整 -----------------------------------36 12 旅馆模式 ----------------------------------------37 13 导线图 ------------------------------------------39 13.1. P 电路板 -----------------------------------39 13.2. PA 电路板 ----------------------------------43 13.3. H，HC 和 TA 电路板 --------------------------45 13.4. G 电路板 -----------------------------------47 13.5. GK，K 和 S 电路板 ---------------------------48 13.6. DG 电路板 ----------------------------------49 13.7. D 电路板 -----------------------------------51 13.8. C1 电路板 ----------------------------------53 13.9. C2 电路板 ----------------------------------54 13.10. SC 电路板 ----------------------------------55 13.11. SU 电路板 ----------------------------------58 13.12. SD 电路板 ----------------------------------59 13.13. SS 电路板 ----------------------------------60 14 方框图和线路图 ----------------------------------62 14.1. 线路图注意事项-----------------------------62 14.2. 主要集成电路方框图-------------------------63 14.3. P 电路板方框图 -----------------------------64 14.4. P 电路板 （1/6）线路图----------------------65 14.5. P 电路板 （2/6）线路图----------------------66 14.6. P 电路板 （3/6）线路图----------------------67 14.7. P 电路板 （4/6）线路图----------------------68 14.8. P 电路板 （5/6）线路图----------------------69 14.9. P 电路板 （6/6）线路图----------------------70 14.10. PA 电路板方框图 ----------------------------71 14.11. PA 电路板 （1/3）线路图---------------------72 14.12. PA 电路板 （2/3）线路图---------------------73 14.13. PA 电路板 （3/3）线路图---------------------74 14.14. H 和 TA 电路板方框图 ------------------------75 14.15. H 电路板 （1/3）线路图----------------------76 14.16. H 电路板 （2/3）线路图----------------------77 14.17. H 电路板 （3/3）线路图----------------------78 14.18. TA 电路板线路图 ----------------------------79 14.19. G，GK，HC 和 K 电路板方框图 -----------------80 14.20. G 电路板线路图 -----------------------------81 14.21. GK 和 K 电路板线路图 ------------------------82 14.22. HC 电路板线路图 ----------------------------83 14.23. DG 电路板 （1/3）方框图---------------------84 14.24. DG 电路板 （2/3）方框图---------------------85 14.25. DG 电路板 （3/3）方框图---------------------86 14.26. DG 电路板 （1/8）线路图---------------------87 14.27. DG 电路板 （2/8）线路图---------------------88 14.28. DG 电路板 （3/8）线路图---------------------89 14.29. DG 电路板 （4/8）线路图---------------------90 14.30. DG 电路板 （5/8）线路图---------------------91 14.31. DG 电路板 （6/8）线路图---------------------92 4 14.32. DG 电路板 （7/8）线路图 -------------------- 93 14.33. DG 电路板 （8/8）线路图 -------------------- 94 14.34. D 电路板 （1/2）方框图 --------------------- 95 14.35. D 电路板 （2/2）方框图 --------------------- 96 14.36. D 电路板 （1/8）线路图 --------------------- 97 14.37. D 电路板 （2/8）线路图 --------------------- 98 14.38. D 电路板 （3/8）线路图 --------------------- 99 14.39. D 电路板 （4/8）线路图 -------------------- 100 14.40. D 电路板 （5/8）线路图 -------------------- 101 14.41. D 电路板 （6/8）线路图 -------------------- 102 14.42. D 电路板 （7/8）线路图 -------------------- 103 14.43. D 电路板 （8/8）线路图 -------------------- 104 14.44. C1 电路板方框图--------------------------- 105 14.45. C1 电路板 （1/4）线路图 ------------------- 106 14.46. C1 电路板 （2/4）线路图 ------------------- 107 14.47. C1 电路板 （3/4）线路图 ------------------- 108 14.48. C1 电路板 （4/4）线路图 ------------------- 109 14.49. C2 电路板方框图--------------------------- 110 14.50. C2 电路板 （1/3）线路图 ------------------- 111 14.51. C2 电路板 （2/3）线路图 ------------------- 112 14.52. C2 电路板 （3/3）线路图 --------------------113 14.53. SC，SU 和 SD 电路板方框图 ------------------114 14.54. SC 电路板 （1/2）线路图 --------------------115 14.55. SC 电路板 （2/2）线路图 --------------------116 14.56. SU 电路板 （1/2）线路图 --------------------117 14.57. SU 电路板 （2/2）线路图 --------------------118 14.58. SD 电路板 （1/2）线路图 --------------------119 14.59. SD 电路板 （2/2）线路图 --------------------120 14.60. SS 和 S 电路板方框图 -----------------------121 14.61. SS 和 S 电路板线路图 -----------------------122 15 部件布置及机械部件更换清单 ---------------------123 15.1. 部件布置 ----------------------------------123 15.2. 包装分解图 (1) ----------------------------124 15.3. 包装分解图 (2) ----------------------------125 15.4. 包装分解图 (3) ----------------------------126 15.5. 维修部品表 --------------------------------127 16 电器部件更换清单--------------------------------128 16.1. 更换部件清单注意事项 ----------------------128 16.2. 电器部件更换清单 --------------------------129 5 1 可显示的输入信号 标记：可适用的分量 （Y, PB, PR）、HDMI 及 PC （D-Sub 15P）输入信号 注： • 不属于上述规格的信号可能无法正确显示。 • 上述信号均经重新格式化，以达到最佳观看效果。 6 2 安全警告 2.1. 一般准则 1. 维修时，检查引线的外观。如发现短路，更换所有因短路而过热或被损坏的部件。 2. 维修后，检查并确认所有的保护装置，如：绝缘隔障、绝缘纸、屏蔽等安装正确。 3. 维修后，进行以下漏电检查，以免用户遭受触电危险。 2.1.1. 漏电冷检查 1. 拔掉 AC 电源线，然后在插头的两个支脚间接上一根跳线。 2. 用欧姆计测量接上跳线的 AC 插头与设备上各外露的金属机 型部分（如螺丝头、连接端、调节杆等）之间的电阻值。外 露金属部分有至机芯的回路时，读数应在 1M Ω和 5.2M Ω之 间。 当外露金属部分没有至机芯的回路时，读数必定为 。 2.1.2. 漏电热检查 （见图 1） 1. 将 AC 电源线直接插入 AC 电源插座。进行检查时，请勿使 用隔离变压器。 2. 在设备上各外露金属部分和良好接地 （如水管）之间连接 一个 1.5k Ω，10W 的电阻，并与 0.15 μ F 的电容器并联， 如图 1 所示。 3. 用一只 1000 Ω /V 或灵敏度更高的 AC 电压表测量穿过电阻 的电势。 4. 检查各外露金属部件并测量各点的电压。 5. 变换 AC 插座中的 AC 插头，并重复上述各项测量。 6. 任何点上的电势都不能超过 0.75V RMS。 漏电测试仪 （Simpson229 型或类似型号）可用于热检测， 其中漏电绝不能超过 0.5mA。当测量值超出规定的限制时， 可能会引起触电。所以必须在机器返回用户手中之前对其 进行修理和再检测。 7 3 静电敏感设备 (ES) 的静电放 电保护 (ESD) 一些半导体（固态）装置很容易被静电损坏。这些装置通称为静电敏感装置（ES）。典型的 ES 装置有集成电路和一些场效应晶体管以 及半导体 “芯片”组件。以下方法通常被用来减少由于静电释放 （ESD） 所造成的组件损坏。 1. 在处理任何半导体组件或是配备有半导体组件的设备之前，接触已知地线以排除身体上的静电。或者戴上市面上可购买到的抗静 电腕带，但是在待检设备通电之前应将其拿掉，以免遭受电击。 2. 在拆卸配有静电敏感装置的电气组件后，请将组件放置于导体表面上 （如铝箔），以防止聚集静电或组件外露。 3. 仅使用末端接地的烙铁焊接或拆焊静电敏感装置。 4. 仅使用防静电拆焊装置。不属于 “防静电 （静电释放保护）”的拆焊装置可能会产生足以损坏静电敏感装置的电荷。 5. 禁止使用氟里昂驱动化学物质。它们能产生足以损坏静电敏感装置的电荷。 6. 在准备立即安装之前，才能拆开静电敏感备换装置的保护性包装，取出备换静电敏感装置。（大多数备换静电敏感装置都使用导 电泡沫、铝箔或类似导电性材料包装，其导线被短接。） 7. 从备换静电敏感装置导线上取下防护性材料前，使防护性材料接触机芯或即将安装的电路组件。 注意： 确定机芯或电路无电源，并遵守其它所有安全注意事项。 8. 在处理未包装的备换静电敏感装置时，尽量减少身体活动。（否则，如衣物纤维的摩擦或从铺有地毯的地面抬起脚等动作都会产 生足以损坏静电敏感装置的静电 （静电释放））。 8 4 关于无铅焊接 (PbF) 注：在元素周期表中，铅用 Pb 表示。 在下文中，Pb 表示有铅焊接，PbF 表示无铅焊接。 在制造流程中使用和下文中介绍的无铅焊接 （Sn+Ag+Cu）。 即：锡 （Sn），银 （Ag）和铜 （Cu），其他类型也可使用。 出于环境保护的考虑，本设备制造中使用了无铅焊接工艺。我们建议在维修和修理工作中最好使用无铅焊接，不过也允许使用有铅焊 接。 使用无铅焊接工艺制造的印刷电路板背面的树叶形符号 内有 PbF 字样。 注意： • 无铅焊接的熔点比标准焊接的熔点高。通常熔点超过 50-70°F （30-40°C）。 请使用高温烙铁，并将其温度设为 700±20°F （370±10°C）。 • 当温度过高 （约 1100°F 或 600°C）时，无铅焊料可能会发生喷溅。 如果必须使用有铅焊接，请在焊接前先全部去除焊脚或焊区上的无铅焊料。如果做到这点实际操作困难，则确保无铅焊料加热到熔 化后再进行有铅焊接。 • 在对双面电路板进行无铅焊接后，请检查部件侧部是否有过量焊料，否则会流到另一侧。（见下图） 推荐的无铅焊料 有几种无铅焊料可供选购。本产品使用 Sn+Ag+Cu( 锡 + 银 + 铜 ) 焊料。 9 5 维修提示 电路板名称 功能 电路板名称 功能 P 电源 SC 扫描驱动 PA DC-DC 转换 , 扬声器输出，音频放大， SU 扫描输出 ( 上 ) 风扇控制 SD 扫描输出 ( 下 ) H AV 端口，AV 切换 SS 维持驱动 DG 数字信号处理器 , Micon，HDMI 接口 K 遥控接收器，电源指示灯 D 格式转换，等离子 AI， 子场处理器 S 电源开关 HC 夹具连接 G 前部端子 C1 数据驱动 ( 右下 ) GK 按键开关 C2 数据驱动 ( 左下 ) TA 高频调谐器 10 6 等离子显示屏更换方式 6.1. 取下后盖 1. 见维修提示 （请参见第 5 章节） 6.2. 取下风扇 1. 断开线束连接件。 2. 松开螺丝 （×3 每个）并取下风扇。 3. 取下后端子盖。 6.3. 取下后端子盖 1. 松开螺丝 （×11 ,， × 4 ， × 2 ）。 2. 取下后端子盖。 6.4. 取下 P 板 注意： 由于电解电容器放电原因，电源切断后等候一分钟再取下 P.C.B.。 1. 松开电缆线夹，以取出电缆。 2. 断开连接件 (P2, P5, P9, P10, P11, P12, P23 和 P25)。 3. 松开螺丝 （×6 ），取下 P 板。 6.5. 取下 PA 板 1. 松开电缆线夹，以取出电缆。 2. 断开连接件 (PA2, PA5, PA10, PA31, PA32, PA33, PA34 和 PA40)。 3. 断开柔性电缆 （PA20）。 4. 松开螺丝 （×4 ）并取出接地线。 5. 取下 PA 板。 11 6.6. 取下调谐器单元 1. 松开电缆线夹，以取出电缆。 2. 断开连接件 (DG5, G51, PA40 和接地线 )。 3. 断开柔性电缆 (DG3 和 PA20)。 4. 松开螺丝 （×4 ），并取下调谐器单元。 6.7. 取下 DG 板 1. 断开连接件 （DG2）。 2. 断开柔性电缆 (DG1, DG15 和 DG20)。 3. 松开螺丝 （×8 ），并取下 DG 板。 6.8. 取下 TA 板 1. 断开调谐器电缆。 2. 松开螺丝 （×1 ），并取下 TA 板。 6.9. 取下 H 板 1. 取下 TA 板。（请参见第 6.8 章节） 2. 松开电缆线夹，以取出电缆。 3. 断开连接件 (H2, H40 和 H51)。 4. 断开柔性电缆 （H1）。 5. 松开螺丝 （×5 ），并取下 H 板。 12 6.10. 取下 HC 板 1. 断开柔性电缆 （HC15）。 2. 松开螺丝 （×2 ），并取下 HC 板。 6.11. 取下 D 板 1. 取下调谐器组件。（见第 6.6 章节） 2. 断开连接件 (D5, D20 和 D25)。 3. 断开柔性电缆 (D3, D33 和 D34)。 4. 松开螺丝 （×4 ），并取下 D 板。。 6.12. 取下 SU 板 1. 松开螺丝 （×2 ）。 2. 断开柔性电缆 (SU1, SU2, SU3 和 SU4) 并取下桥式联接器 （SU45）。 3. 将 SU 板移到左边，使其与 SC 板的连接件（SC41-SU41）断 开，然后取下 SU 板。 6.13. 取下 SD 板 1. 松开螺丝 （×2 ）。 2. 断开柔性电缆 (SD1, SD2, SD3 和 SD4)，并取下桥式连接器 （SD46）。 3. 将 SD 板移到左边，使其与 SC 板的连接件 （(SC42-SD42） 断开，然后取下 SD 板。 13 6.14. 取下 SC 板 1. 松开电缆线夹，以取出电缆。 2. 断开连接件 (SC2, SC20 和 SC23)。 3. 松开螺丝 （×6 ），并取下 SC 板。 6.15. 取下 SS 板 1. 断开连接件 (SS11, SS12, SS23 和 SS34)。 2. 断开柔性电缆 (SS41, SS42, SS43 和 SS44)。 3. 松开螺丝 （×6 ），并取下 SS 板。 6.16. 取下前支架 1. 松开电缆线夹，以取出电缆。 2. 断开连接件 (G1 和 G51)。 3. 松开螺丝 （×5 ），并取下前支架。 6.17. 取下 G 板和 GK 板 1. 取下前支架。（见第 6.16 章节） 2. 松开螺丝 （×3 ），并取下金属盖。 3. 松开螺丝 （×3 ），并取下前面金属框。 4. 松开螺丝 （×3 ），并断开连接件 (G3-GK3)。 5. 取下 G 板和 GK 板。 14 6.18. 取下左右扬声器 1. 断开中继连接件。 2. 松开螺丝 （×4 ）每个），并取下左右扬声器。 6.19. 取下 S 板 1. 断开连接件 （S1）。 2. 松开螺丝 （×2 ），并取下 S 板金属框。 3. 松开螺丝 （×2 ），并取下 S 板。 6.20. 取下 K 板 1. 松开电缆线夹，以取出电缆。 2. 断开连接件 (G1)。（见第 6.16 和 6.19 章节） 3. 松开螺丝 （×2 ），并取下 K 板。 6.21. 取下支撑架 1. 将等离子显示屏从维修架上取下，放置在类似桌子 （铺有 软布）的表面上，并且显示屏表面朝下。 2. 松开支撑架 （左、右）固定螺丝 （×6 每个），并取下支 架 （左、右）。 6.22. 取下 C1 板 1. 取下调谐器单元。（见第 6.6 章节） 2. 松开电缆线夹，以取出电缆。 3. 松开柔性电缆支架固定螺丝 （×12 ）。 4. 断开柔性电缆 (CB1, CB2, CB3，CB4，CB5 和 CB6)。 5. 断开柔性电缆 (C11 和 C12)。 6. 松开螺丝 （×4 ）并取下 C1 板。 6.23. 取下 C2 板 1. 取下调谐器单元。（见第 6.6 章节） 2. 松开电缆线夹，以取出电缆。 3. 松开柔性电缆支架固定螺丝 （×10 ）。 4. 断开柔性电缆 (CB5, CB6, CB7，CB8，CB9，CB10，CB11)。 5. 断开柔性电缆 (C21 和 C22)。 6. 断开连接件 （C23）。 7. 松开螺丝 （×4 ）并取下 C2 板。 15 6.24. 取下 AC 接入口 1. 松开电缆线夹，取下出电缆。 2. 断开连接件 （P9）。 3. 松开螺丝 （×3 ），并取下 AC 接入口。 6.25. 从前面框（玻璃）上取下等离子显 示屏 1. 取下前面框和等离子显示屏固定螺丝 （×6 ）。 2. 取下前面框和支撑架固定螺丝 （×4 ）。 3. 从前面框上取下等离子显示屏时，向上拉前面框底部并抬 起，即可取出。 6.26. 安装新的等离子显示屏 1. 将新的等离子显示屏放置在铺有软布的桌子上，并且等离 子显示屏表面朝下。 2. 安装 C1 板和 C2 板，连接等离子显示屏的柔性电缆（× 11） 至 C1 和 C2 板，并固定柔性电缆支架。 3. 安装挂钩 （左、右） ，并将支撑架 （左、右）装配到新的 等离子显示屏上。 4. 将等离子显示屏放置到维修架上。 5. 将面框和 P.C.B. 板等装到新的等离子显示屏上。 * 安装面框时，注意不要让前玻璃和等离子显示屏之间有碎 屑、灰尘或杂质存在。 16 7 导线布置 7.1. 导线 (1) 如图中所示进行布线。 注意：在接喇叭线时，请注意喇叭线的极性。 17 7.2. 导线 (2) 如图中所示进行布线。 18 7.3. 导线 (3) 如图中所示进行布线。 19 7.4. 导线 (4) 如图中所示进行布线。 20 7.5. 导线 (5) 如图中所示进行布线。 21 8 自检 1. 自检用于自动检查电视机的总线和十六进制码。 2. 要进入自检模式，按下电视机前端的 (-/v) 键，同时按下遥控器上的 “菜单”键，显示屏将会显示： 如果 CCU 端口经过检测，发现异常或位置不正确，则 “--”将会显示在 “O.K.”的位置。 显示 参考号 说明 电路板 MEM IC1102 内存 DG 电路板 Gc5 IC4037 GC5 处理器 DG 电路板 AVSW 1 IC3005 视频开关 H 电路板 AVSW 2 IC2105 音频开关 H 电路板 Tun1 TU001 调谐器 TA 电路板 MSP IC2106 多声音处理器 H 电路板 PANEL IC9003 Convert Micon D 电路板 HDMI IC4026 HDMI I/F 接收器 DG 电路板 ADV IC4019 10bit A/D DG 电路板 22 8.1. 发光二极管 LED 电源定时闪亮曲线图表 1. 主题 发光二极管闪烁次数图信息。 2. 内容 当设备出现异常时，保护电路将运行并将设备复位到待机状态。此时，通过本机前显示屏上的电源 LED 闪烁次数便可识别出故障 部位。 23 8.2. 无电源 LED 无电源指示有 3 种情况： 1. 不亮 2. 绿灯亮，几秒钟后转为红灯闪烁。 3. 只有红灯亮。 24 8.3. 无图像 25 8.4. 显示屏局部故障 等离子显示屏屏幕上可能会出现局部故障。图 1 是各局部可能会出现故障的印刷电路板。 26 9 维修模式功能 MPU 通过此机型的 IIC 总线来控制各 IIC 模式的功能转换。以下各项可在维修模式下通过遥控来进行设置和调节。 9.1. 如何进入维修模式 1 1. 将音量设置为最小，将定时关机设置为 15 分钟。 2. 同时按下电视机上的 DOWN （下） 键和遥控器上的 RECALL[ ] 键。 9.2. 如何进入维修模式 2 1. 进入维修模式 1。 2. 同时按下电视机上的 DOWN （下） 键和遥控器上的静音 [ ] 键。 注： 要退出维修模式，按下遥控器上的 N 或 Power 键。 27 28 9.3. 选项说明 PV65C 选项 1 0F b0 1 彩色制式 自动 (1) b1 1 SECAM(1) b2 1 NTSC(1) b3 1 M.NTSC(1) b4 0 A2 选择 6.5MHz 5.742MHz(0) 6.742MHz(1) b5 0 SIF 4.5/5.5/6.0/6.5(0)，5.5/6.0/6.5(1) b6 0 5.5/6.5(2)，6.0/6.5(3) b7 0 闲置 选项 2 E2 b0 0 A2 启动 启动 (1) b1 1 未使用 b2 0 未使用 b3 0 未使用 b4 0 NICAM 启动 启动 (1) b5 1 未使用 b6 1 未使用 b7 1 未使用 选项 3 1A b0 0 SASO 启动 SASO 启动 (1) b1 1 微调 启动 (1) b2 0 搜索速度 慢 (1) 快 (0) b3 1 调谐器 MACO 调谐器 (1), 其它 (0) b4 1 HYPER 仅 UHF(0), UHF/VHF(1) b5 0 IF I2C 12C 控制调谐器 IF 模块 (1) b6 0 NICAM C4 比特 启动 (1) b7 0 蓝底 菜单中蓝背景开 / 关选择 （0） 选项 4 08 b0 0 ASPECT 自动 启动 (1) b1 0 S1/S2 启动 启动 (1) b2 0 ID-1 启动 (1) b3 1 用户比例调整 启动 (1) b4 0 用户比例调整 14:9 启动 (1) b5 0 ALBD 14:9 14:9 启动 , self wide (1) 时 Zoom 3 未启动 / self wide (0) 时 Zoom1, Zoom 3 启动 b6 0 TEXT 启动 (1) b7 0 TEXT TOP TOP 启动 (1) 选项 5 23 b0 1 CH 闪烁 闪烁启动 (1) b1 1 AV 闪烁 闪烁启动 (1) b2 0 静音 静音启动 (0) b3 0 副图像 无副图像 (0)，有副图像 (1) b4 0 2 调谐器 2 调谐器 (1)，1 调谐器 (0) b5 1 AV 输入 3 旋转 (1)/2 无前 RCA 旋转 (0) b6 0 显示屏 ( 液晶 ) Samsung 显示屏 (1)/SHARP 显示屏 (0) b7 0 大尺寸 ( 液晶 ) 液晶 32(1)/26(0) 选项 6 A0 b0 0 SD 模块 有 SD 模块 (1) b1 0 SD 模块外部 Rec(PAL) SD 模块外部 Rec(NTSC) SD 模块外部 Rec.(SECAM) 启动 (1) b2 0 启动 (1) b3 0 启动 (1) b4 0 IDTV 启动 (1) b5 1 HDMI 启动 (1) b6 0 外部 HV 输入 无 HV 输入 (0)/ 有 HV 输入 (1) b7 1 PC 启动 (1) 选项 7 61 b0 1 亚洲 亚洲 (1), 欧洲 (0) b1 0 澳大利亚 未使用 b2 0 爱尔兰 / 印度 爱尔兰 (1) b3 0 英国 / 韩国 英国 (1) b4 0 语言 1 未使用 b5 1 语言 2 未使用 b6 1 较低 POS 未使用 b7 0 用户 ID 未使用 29 PV65C 选项 8 40 欧洲选项 b0 0 ACI 所有国家 ACI 启动 (1)，仅荷兰 (0) b1 0 ACI 自动 MP ACI 自动多插件启动 (1) b2 0 ACI 补偿 VCR 程序的 ACI 补偿启动 (1) b3 0 供电 EC 模式 通电 EC 启动 (1) b4 0 AV 接线 可在菜单中选择 Q-Link 关 (1) b5 0 音量调节 启动电视音量调节 (1) b6 1 MPX/NICAM 显示器 显示器 NICAM(0)，显示器 MPX(1) b7 0 Albd 复位 关 启动 (1) 选项 9 FF b0 1 CH 方案 亚洲 / 中东 / 香港 / 英国 / 中国 (1) b1 1 新西兰 / 印度尼西亚 (1) b2 1 澳大利亚 (1) b3 1 东欧 (1) b4 1 SPECIAL (1) b5 1 美国 (1) b6 1 CATV(1) b7 1 日本 (1) 选项 10 6F b0 1 NICAM 优先 亚洲 / 中东 (1) b1 1 香港 / 英国 (1) b2 1 中国 (1) b3 1 新西兰 / 印度 (1) b4 0 奥地利 (1) b5 1 东欧 (1) b6 1 SPECIAL (1) b7 0 HDMI AVI Aspect 启动 (1) 选项 11 4F 其它 b0 1 Remocon 类型 Delux(1)/ 导线 (0) b1 1 环境 AI(PDP) 启动，有自动视图模式 (1)/ 未启动，不带自动浏览模式 (0) b2 1 WSS14:9 关闭 WSS14:9 关闭 (1) b3 1 儿童锁码 儿童锁码开： 调谐菜单跳过 （1） b4 0 b5 0 对比 AI 启动 (1) b6 1 水平位置维修 启动 (1) b7 0 垂直位置维修 启动 (1) 选项 12 09 其它 b0 1 宽高比最新记忆 单个信号源 （1）/ 所有信号源 （0） b1 0 保留 b2 0 TEXT 频道刷新 刷新启动 （1）/ 关闭 （0） b3 0 静止 1: 启动 /0： 启动 b4 0 LATIN Latin: SAP/ 固定 SIF 4.5MHz/PAL-M,N/CC/ 黑色电平 / 语言 b5 0 SRS 启动 (1) b6 0 HDMI Quali 电视 启动 (0) b7 0 HDMI EC 功能 启动 (1) 选项 13 00 其它 b0 0 DVB ALBD 启动 (1) b1 0 HDMI 端口 启动 (0) 2 端口模式 / (1) 1 端口模式 ( 仅适用于 TV MCU 端口设置 ) b2 0 HDMI 格式错误屏显 显示 (0)/ 未显示 (1) b3 0 CEC 控制 启动 (1) b4 0 宽高比 4:3 全屏 启动 (0) b5 0 FTZ 启动 (1) b6 0 b7 0 30 10 调整步骤 10.1. 驱动器设置 10.1.1. 项目 / 准备 1. 输入白色信号到等离子显示屏视频。 2. 如下设定图像控制： 图像菜单：鲜艳 图像：+30 宽高比：全屏 注意 1. 首先进行 Vsus 调整。 2. Vad 调整确认后，再确定 Vscn 电压。 当 Vad = -90V 时，Vscn 的电压为 50V ± 4V。 10.1.2. 调整 参照显示屏数据标牌上的显示屏数据，调整驱动器各部分的电 压。 * 见显示屏标牌 名称 测试点 电压 调整点 备注 Vsus TPVSUS(SS) Vsus ± 2V VR251(P) * Ve TPVE(SS) Ve ± 2V VR6000(SS) * Vset TPVSET(SC) 240V ± 7V 固定 Vad TPVAD(SC) -150V ± 1V VR6600(SC) Vscn TPVSCN(SC) Vad + 143V ± 4V 固定 Vda TPVDA(SS) 75V ± 1V 固定 Vdat P12-1,5(P) 75.5V ± 0.1V R665(P) PFC C446(+)(-) 396V ± 0.5V R443(P) Vlow C555(+)(-) 78.5V ± 0.1V R661(P) Vda 负载 电流： 0.4A 31 10.2. 初始化脉冲调整 1. 输入白色信号到等离子显示屏视频。 2. 如下设定图像控制： 图像菜单：鲜艳 图像：+25 宽高比：全屏 3. 连接示波器至测试点 TPSC1 （T2），并调整 VR6602 至 195+10μ Sec。 10.3. P.C.B. （印刷电路版）更换 10.3.1. 注意 1. 由于电解电容器放电原因，电源切断后等候一分钟再取下 P.C.B.。 10.3.2. P.C.B. 更换后进行快速调整 使用万用表调整以下电压。 * 见显示屏标牌。 注意： 请勿将 Vsus 设置到 Ve 以下，以防损坏 PCB 板。 测试点 调整点 等级 T2 TPSC1(SC) VR6602 (SC) 195 ± 10μ Sec P.C.B. 名称 测试点 电压 调整点 备注 P 电路板 Vsus TPVSUS(SS) Vsus ± 2V R628(P) * Vdat P12-1,5(SS) 75.5V ± 0.1V R665(P) PFC C446(+)(-)(P) 396V ± 0.5V R443(P) Vlow C445(+)(-)(P) 78.5V ± 0.1V R661(P) Vad 负载电流：0.4A SC 电路板 Vad TPVAD(SC) -105V ± 1V VR6600(SC) SS 电路板 Ve TPVE(SS) Ve ± 2V VR6000(SS) * D,DG 电路板 NTSC, PAL, HD, PC 和 625i 信号的白平衡、背景设定和副亮度。 32 10.4. 调整点位置 10.5. 测试点位置 33 11 微调 11.1. PAL 显示屏白平衡调整 仪器名称 连接 备注 黑白模式 彩色分析仪 （Minolta CA-100 或同等产品） RF 输入 显示屏表面 用户设定：标准 步骤 备注 确保充分老练 15 分钟以上。 确保前面板已经安装在整机上。 确认调整之前无彩色信号显示。 将彩色分析仪放置在有轻微色差的地方。 打开电源后 10 分钟之内完成调整。 通过老炼处理等不能完成调整时，要重新打开电源。 1. 显示白平衡图像。 2. 确认色温设定为 “冷色”。 3. 进入 < 维修菜单 1>。 4. 用红键或绿键选择 “G-CUTOFF”，并通过黄键或蓝键将其设定到 “128”。 同样，“B-CUTOFF”和 “R-CUTOFF”设定为 “128”。 5. 设定 “G-DRIVE”为 “224”。 6. 触摸彩色分析仪的信号接收器到高亮显示窗口的中间位置，然后调整 B 驱动和 R 驱动，将 x, y 的值调整为表 1 中色温度 （冷色）的值。 7. 设定 “ALL-DRIVE”为 “252”。 8. 将色调设定设置为 “标准”。 9. 设定 G cutoff,B cutoff 和 R cutoff 为 “128”。 10. 确定 G 驱动为 “224”。 11. 调整 B 驱动和 R 驱动，将高亮显示窗口中的 x, y 的值调整为下表中色温 （标准）的值。 12. 设定 “ALL-DRIVE”为 “252”。 13. 设色调设定设置为 “暖色”。 14. 设定 G cutoff,B cutoff 和 R cutoff 为 “128”。 15. 确定 G 驱动为 “224”。 16. 调整 B 驱动和 R 驱动，将高亮显示窗口中的 x, y 的值调整为下表 1 中色温 （暖色）的值。 17. 设定 “ALL-DRIVE”为 “252”。 图像菜单：最佳 宽高比：16:9 高亮显示部分 信号振幅 75% 34 11.2. HD 白平衡调整 仪器名称 连接 备注 黑白模式 彩色分析仪 （Minolta CA-100 或同等产品） RF 输入 显示屏表面 用户设定：标准 步骤 备注 确保充分老练 15 分钟以上。 确保前面板已经安装在整机上。 确认调整之前无彩色信号显示。 将彩色分析仪放置在有轻微色差的地方。 打开电源后 10 分钟之内完成调整。 通过老炼处理等不能完成调整时，要重新打开电源。 1. 显示白平衡图像。 2. 确认色温设定为 “冷色”。 3. 进入 < 维修菜单 1>。 4. 用红键或绿键选择 “G-CUTOFF”，并通过黄键或蓝键将其设定到 “128”。 同样，“B-CUTOFF”和 “R-CUTOFF”设定为 “128”。 5. 设定 “G-DRIVE”为 “224”。 6. 触摸彩色分析仪的信号接收器到高亮显示窗口的中间位置，然后调整 B 驱动和 R 驱动，将 x, y 的值调整为表 1 中色温度 （冷色）的值。 7. 设定 “ALL-DRIVE”为 “252”。 8. 将色调设定设置为 “标准”。 9. 设定 G cutoff,B cutoff 和 R cutoff 为 “128”。 10. 确定 G 驱动为 “224”。 11. 调整 B 驱动和 R 驱动，将高亮显示窗口中的 x, y 的值调整为下表中色温 （标准）的值。 12. 设定 “ALL-DRIVE”为 “252”。 13. 设色调设定设置为 “暖色”。 14. 设定 G cutoff,B cutoff 和 R cutoff 为 “128”。 15. 确定 G 驱动为 “224”。 16. 调整 B 驱动和 R 驱动，将高亮显示窗口中的 x, y 的值调整为下表 1 中色温 （暖色）的值。 17. 设定 “ALL-DRIVE”为 “252”。 图像菜单：最佳 宽高比：16:9 高亮显示部分 信号振幅 75% • 冷色调设定值不同于日本型号。 35 11.3. 副亮度调整 仪器名称 连接 备注 1. PAL 信号发生器 （或 RF） 连接到输入端子 用户设定：标准 步骤 备注 每个信号的色彩平衡调整都已完成。 务必在暗室中调整。 接通电源 10 分钟内完成调整。 时效之内无法完成调整时请再次打开电源。 1. 显示通过视频输入调整亮度的模式。 2. 通过 < 维修菜单 1> 中的 “Sub-Bright”进行调整，使图中第 6 级灰度显示，而第 7 级灰度 不显示。 数据 副亮度总共有 12bit 的数据地址 LSB 8bit A2-0116 bit7-0 MSB 4bit A2-0117 bit3-0 图像菜单：最佳 彩色平衡：标准 宽高比：16:9 36 11.4. ABL 调整 仪器名称 连接 备注 1. HD 信号发射器 （或引导器 1080i/No.9 信号） 2. 功率计 分量输入端子 将调整设备的交流电源连接到功率计。 步骤 备注 • 确保在调整之前经过 30 分钟以上的老炼。 （运行期间或之后请勿关闭设备。） • 电压 230V 50Hz （1% 偏差） • 音量为最小，屏幕尺寸为 “16:9” 分量输入，最佳，标准 1. 连接设备的交流电源至功率计。 2. 输入信号 ( 上半部：彩色条形图，下半部：10 级灰度 )。 3. 在 < 维修模式 1> 中选择 “PWRCTL”。 4. 调整 PWRCTL，使机器的功耗为 355 ± 10W 备注 1. 功率和数据成反比。 （降低数据，功率上升。） 2. 有可能调整值在两处均可使用，此时调整 PWRCTL 数值大的那种情况。 37 12 旅馆模式 1. 目的 设置旅馆功能。 2. 进入指令 • 进入维修模式 2。 • 同时按下电视机上的 DOWN（下）[-/V] 键和遥控器上的静音 键，进入 EAROM EDITOR 模式。 • 按红 / 绿键，在各地址间上下选择。 • 按黄 / 蓝键在各地址间左右选择。 • 按节目键在各页之间上下选择。 • 按黄 / 蓝键来改变功能值。 • 设定 EEPROM （ADDRESS 0BAF）为 01。 • 按 OK 键，存储数据。 通过遥控器上的开关键来进行开 / 关机操作。 由此进入旅馆模式。 3. 退出指令 • 首先，设定 EEPROM （ADDRESS 0BAF）为 00。 然后，通过遥控器上的开关键来进行开关机操作。 之后便退出旅馆模式。 4. 进入旅馆模式设置菜单指令 • 前提：EEPROM (ADDRESS 0BAF) 的数据应为 01。 为了显示旅馆模式设置菜单，请输入以下指令 （在 2 秒钟 内） 之后便进入旅馆模式。 5. 旅馆模式设置菜单说明 6. 退出旅馆模式 从壁装插座上拔出 AC 电源线 项目 功能 初始输入 选择输入信号模式。 每次接通电源后都设置此信号。 选项： Off/TV/AV1/AV2/AV3/AV4/PC/HDMI1/HDMI2 关： • 以最后一次存储为准。 • PC: VGA 可选 初始音量等级 每次接通电源后都设置音量 选项 / 范围： Off/0 到 100 • 关 : 以最后一次储存为准。 最大音量等级 调节最大音量。 范围： 0 到 100 初始位置 选择频道号。 选项： Off/0 到 99 • 关 : 以最后一次存储为准。 键锁定 选择按键键入条件。 选项： Off/SETUP/MENU/ALL • 关 : 所有按键有效 • 设定：只有 F 键无效 （菜单中调谐状态无） • 菜单：只有 F 键无效 （只可选择音量 / 静音。） • 所有：所有按键全部无效。 遥控锁定 选择遥控键入条件。 选项： Off/SETUP/MENU • 关 : 所有按键有效 • 设置：只有设置菜单无效 • 菜单：图像 / 声音 / 设置菜单无效 62 14 方框图和线路图 14.1. 线路图注意事项 63 14.2. 主要集成电路方框图 TH-42PV65C Main Block Diagram TH-42PV65C Main Block Diagram SC23 64 VDA S.R. VDA 5V 64 VOLTAGE SC2 PA20 +15V S.R. 64 VIDEO IN 12V DG1 VOLTAGE DG2 PA SOS PROTECTION(SOS) POWER SUPPLY DC/DC PA40 ADDRESS SCAN DRIVE S.R SPEAKER SUSTAIN SD S.R P12 AV4 IN VSUS S.R. S.R. DG5 CONVERTER PA5 S.R 64 64 DG20 VOLTAGE SC20 DATA DRIVER(LEFT) S.R POWER LED 15V AV4 IN PA AUDIO IN PA10 POWER ERASE S.R SOUND SOS VDA P25 RECTIFIER CONTROL LED P2 VOLTAGE PROCESS SCAN OUT S.R. 64 VSUS G SUSTAIN SC +15V SPEAKER G3 G51 PULSE 64 P STBY5V_M S.R SCAN OUT L S1 VOLTAGE K REMOTE RECEIVER 64 C21 S.R. SS12 DC-DC CONVERTER C1 CONTROL F_STBY-14V POWER SOS P10 SUSTAIN P11 K1 G1 S-VIDEO IN VOLTAGE RECTIFIER S.R. S.R Vda-75V L STB12V DATA DRIVER(RIGHT) SS CONTROL FACTOR SS_SOS8 KEY PA34 S.R. VSUS P9 S.R CONTROL FAN SOS P23 PULSE C12 SOS6 PA31 P5 PULSE SCAN 15V C2 PROCESS SUSTAIN SCAN STANDBY PA2 STANDBY 64 SU CONTROL SUSTAIN DRIVE SOS7 AC CORD OSD DC POWER 64 SS11 VOLTAGE SPEAKER C23 R REMOTE RECEIVER DG3 S.R MCU VOLTAGE (VE) AMP Vda S.R RECTIFIER C11 PULSE PULSE GK3 GK KEY 64 S.R STB5V R SS23 15V C22 64 MAIN S.R RECTIFIER GENERATOR SCAN L/R H6 L/R V/Y,PB.PR INPUT C,V AUDIO VIDEO AV1 OUT DC POWER MAIN H2 VIDEO OUT V H SELECT TUNER L/R AV2 AV SWITCH,MSP INPUT SIF L/R AUDIO V MSP AUDIO TUNER H1 TA6 PC IN R,G,B AV3 TA OUT IN IN IN L/R H51 SIF SCART AV TERMINAL, L/R H40 L/R SELECT TV-V V/Y,PB.PR R G Y,PB/C,PR,CVBS B RGB PROCESSOR (GC5) LVDS TRANS- MITTER PC_R,G,B L/R DAC HDMI1 IN DG RECEIVER YG/UB AUDIO DIGITAL SIGNAL PROCESSOR HDMI I/F HDMI A/D TV_L/R HEADPHONE HP_L/R MAIN_L/R AI SENSOR RECTIFIER FILTER RELAY LINE FILTER LINE +5V +15V PS_SOS SOS SOUND +15V FAN SOS FAN S34 POWER SWITCH STB12V STB_PS STB12V STB_PS STB12V STB_PS S POWER SW HDMI2 IN S.R. S.R. S.R. FLASH PROCESSOR SOS8 SOS7 D34 FORMAT SUB-FIELD PLASMA AI PROCESSOR D25 RECEIVER P3.3V MICOM IIC P2.5V SCAN CONTROL EEPROM D33 DISCHARGE OUTPUT LVDS VIDEO OUTPUT PROCESSOR D5 CONVERTER SOS6/ D3 FLASH SDRAM PROCESSOR DC/DC CONVERTER CONVERTER D PICTURE DATA DRIVE SDRAM FORMAT MEMORY PLASMA AI PICTURE SUSTAIN CONTROL CONTROL CONTROL CONTROL P1.2V DATA IIC D20 RGB RGB PLASMA AI FORMAT CONVERTER SUB-FIELD PROCESSOR FPGA P_ON/OFF 64 14.3. P 电路板方框图 + - + - + D509 X501 4NHz R661 1 2 3 R665 1 2 3 Q408 Q412 D417 D420 D419 C469 R671 C555 R443 1 2 3 D529 D528 D404 D596 D416 D435 D401 D430 D563 D511 D505 R628 Q527 D530 Q413 Q409 D520 D521 D535 1 2 IC408 4 2 1 3 1 3 4 2 1 3 4 2 IC404 IC403 9 2 3 17 8 10 13 1 T401 5 8 7 6 VCC MOS DRIVE CURR DET CURR COMP 2 1 3 4 Q407 Q420 Q404 Q406 R406 D415 IC406 POWER FACTOR CORRECTOR Q535 8 6 10 7 9 2 3 4 1 15 19 24 18 22 23 16 17 21 20 VDD VSS XIN XOUT RESET STB PS PFC DET STB 5 ON/OFF LOW 15 AC GOOD F STB ON V LOW DET AC P DET TV ON/OFF VSUS DET F_STB ON/OFF PS SOS PFC ON/OFF V LOW ON/OFF IC501 1 2 IC502 RESET 1 5 2 4 6 3 2 1 4 Vda P12 +15V +15Vc TO 1 2 6 PA5 P5 4 7 8 1 +15V 2 +15V P23 TO SC23 9 +5Vc TO STBY5V 7 P25 D25 +5Vc 10 Q421 POWER MCU COLD COLD HOT 10 STB_PS Q422 Vda75V 8 STB12V Q509 16 17 15 18 2 +15Vc 1 3 HOT POWER SUPPLY 4 Vda Q508 14 13 PR601 9 6 5 4 3 5 ZCD 7 GD 8 VCC 1 3 VFF 4 CS INV IC509 13 14 12 MAIN RELAY RUSH RELAY VSUS ON/OFF ALL OFF 11 Q559 13 F_STBY_ON ALL_OFF PS_SOS PANEL_MAIN_ON ECO_ON F STB 14V 2 1 3 F STB 14V F STB 14V P10 TO PA10 IC520 PR401 F401 F402 1 4 NEUTRAL RL402 RL403 4 2 4 2 IC412 3 1 1 3 5 16 13 10 17 9 7 SS12 TO T601 T410 T404 D539 LIVE P9 2 POWER COLD HOT AC CORD TO PFC DET STB5V DET VlOW DET VlOW DET Vsus 189V Vlow Vlow Vsus POWER CURCUIT OSC 395V R496 R495 R494 Q418 R497 (350V 40V) PFC OUT Q501 Q502 Q551 Q505 ERROR DET IC506 ON:L H:ON 2 Vda 73V D569 D570 D571 R670 Q541 R650 R649 5V OUT DETECTION COUPLER PHOTO IC405 COUPLER PHOTO CONTROL D579 R579 D549 R666 D551 R545 3 4 1 2 IC505 IC401 COUPLER PHOTO COUPLER DC-DC CONVERTER Csus R533 (3V 1.0V) 178V (1.7A) R526 R527 H:ON OVER VOLTAGE PROTECTION (490V 80V) COUPLER PHOTO COUPLER PHOTO PHOTO OVER VOLTAGE DETECTION (490V 80V) DETECTION 15V OVER VOLTAGE (16V 2V) PROTECTION COUPLER PHOTO SC2 TO GND 1 3 TO 1 Vsus P11 P2 Vsus SS11 3 PFC R444 R475 R441 R442 D441 4 R620 R589 R590 R621 D574 OSC L405 L404 R413 L410 R407 R427 R435 Q434 IC409 (IPD) DC POWER CONTROL 8 Source Source 7 1 Vdd 2 FB Drain 5 4 Vcs 7 14 12 4 16 R472 R473 R465 R464 D418 C446, C447 Q402 L403 Q401 D407 R455 1 3 2 PFC DET AC POWER RESET Q568 3 1 2 ECO STB_PS(12V) R410 PHOTO 4 2 1 3 IC410 COUPLER 7 12 11 3 2 1 IC504 14 15 Q563 Q521 Q569 Q537 Q512 Q561 AC_GOOD 19 1 S 2 S G 3 4 S 8 7 5 6 D D D D 6 4 S 8 5 S 3 D D D 7 G 1 2 S D Q555 Q556 DC/DC CONV. DC/DC CONV. Q558 Q557 Q525,Q530 R534 D585 Q524 OUT 2 1 Vcc PR805 ERROR DET (Vda) IC512 D542 D544 D545 SWITCHING IC510 REGULATOR D513 D512 Q566 13 15 4 6 12 16 2 PHOTO COUPLER 3 4 1 2 IC507 D514 3 1 2 (Vsus) K A Vsus R622 R648 R636 R626 R656 R627 OUT DETECTION (60V 40V) VOLTAGE Q507 2 4 3 5 9 10 6 T402 Q538 R631 R674 R676 3 1 2 K A D572 POWER CIRCUIT Q510 Q564 Q565 Q540 F 5A 250V OSC OSC 9 D531 15 7 D586 4 6 5 D531 D536 RUSH ON Q553 Q554 PR509 Vdat OVER VOLTAGE DETECTION(100V 25V) Q520 Q517 +15Vc +15Vc +15Vs(S) +15Vs(W) +15Vs(W) +15Vc P ERROR DET IC411 ERROR DET IC402 ERROR DET SW SW RECTIFIER SW L:ON RECTIFIER STANDBY POWER SAVE 5V (Vlow) R458 MAIN ON 12V BUFF INV. ECO ON/OFF SW BUFF STB5V ON/OFF STB5V (15V) (F STB 14V) INV. INV. ECO ON VSUS DET INV. INV. VSUS ON/OFF 12V ON/OFF INV. BUFF BUFF BUFF BUFF VSUS DET D602 12V DET SW T407 1 15V GND POWER SOS LED BLINKING : 4TIMES TH-42PV65C P-Board Block Diagram TH-42PV65C P-Board Block Diagram 65 14.4. P 电路板 （1/6）线路图 R472 560K R419 100K R497 12K ZH57 ZH42 R426 10K C443 1000p R473 560K TP5 ZH105 R428 10K TP6 S402 RA-362MS-V7-Y ZH18 RL403 DG12D1-O(M)-2 1 4 2 3 ZN402 D4EAD7510001 R463 33K C423 4700P ZH33 ZH122 R439 12 R417 430K C431 1000P T401 G4D4A0000117 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 R433 12K ZH109 D503 MA165 ZH96 R475 680K D418 02DZ8.2 L405 TF3524V-123Y5R0 1 2 4 3 ZH21 R414 15K D420 S3K60 Z450 EYF52BCY ZH51 R492 0 TP4 C409 2.2uF R450 1000 R437 18K ZH34 R442 680K ZH9 C404 1.0uF ZH120 IC402 TL431A1LPM5 1 2 3 D433 02DZ15 ZN401 ERZVGED621 ZH19 Q422 2SD1819A R471 3.3K C476 100P R451 33K TP8 ZN404 ERZVGAD681 L404 TF3524V-123Y5R0 1 2 4 3 ZH36 C421 1.0 ZH10 ZH32 ZH117 R430 430K D431 RB520 R465 560K ZH20 ZH40 C429 0.047 C478 100P ZH111 D415 D1NS4 R480 47K Z451 EYF52BCY ZH107 C446 200uF/450V ZH58 D419 S3K60 C470 1uF ZH123 R449 0.08 ZH35 C635 0.01 ZH106 R443 2K D429 ERA15-10 R495 560K ZH103 R444 12K R403 1M TP2 2.5mm R455 12K ZH8 ZH48 R453 3M C463 22P R438 330 R421 33K 2.5mm R431 10K C422 0.01 ZH1 2.5mm D417 S3K60 S401 RA-362MS-V7-Y C468 0.01 R436 15K R410 10/5W ZH38 C436 1.0 R456 33K ZH102 TP3 C462 1.0 C461 330p ZH31 C474 100P Q421 2SD1819A C450 0.01 ZH118 ZH49 R452 10K ZH95 R406 ERX12SJ2R2V R493 12 ZH55 C447 200uF/450V R464 33K ZH50 ZH110 R401 10K TP7 R441 680K R494 560K D504 MA165 F401 T8AH 250V ZH16 R692 4700 ZH43 ZH119 ZH92 ZH17 ZH54 ZH2 ZH12 Z453 EYF52BCY ZH7 R402 820 R491 47K C460 330p Q407 HN1B01F C445 1.0 L513 EXCELDR25V R498 0.08 2.5mm R454 10K ZH15 C432 1.0 ZH22 R448 0.08 RL402 DG12D1-O(M)-2 1 4 2 3 C410 0.01 TP1 Q418 2SD1819A D401 D20XB80 R458 4700 Q401 SSM3J14T R440 470K C444 1000p ZH30 Q404 2SB1443 R467 1000 F402 T8AH 250V ZH121 Q402 RTR040N03 C426 470P P9 LIVE 4 NC 3 - 2 NEUTRAL 1 R490 47K ZH108 L403 EXCELSA35T R424 22K C440 10 Z2 K4ZZ01000206 1 ZH37 ZH116 Z452 EYF52BCY R693 10K R415 10K ZH56 C473 100P ZH104 IC406 L6561 1 2 3 4 5 6 7 8 ZH11 R462 430K ZH3 C427 1.0 R496 560K D407 MA111 C428 220P Q420 2SD1819A ZH13 ZH97 ZH4 Q406 RJK5020DPK01 CURR Vcc GND CURR DRIVE COMP MOS DET CAUTION 2 3 D B 4 F 5 E 6 1 8 7 A C 9 CAUTION AC CORD TO P-BOARD TNPA3911AM (1/6) HOT COLD HOT COLD COLD HOT POWER FACTOR CORRECTOR PFC COLD HOT HOT COLD 1 2 3 A B C D F G H I J K E P-BOARD (3/6) TO CORRECTOR FACTOR POWER ERROR DET PFC DET TH-42PV65C P-Board (1 of 6) Schematic Diagram TH-42PV65C P-Board (1 of 6) Schematic Diagram R499 390K 66 14.5. P 电路板 （2/6）线路图 ZH72 ZH65 R600 390 C530 0.033 D531 RF2001T3D P10 F_STBY 1 F_STBY 2 F_STBY 3 GND 4 GND 5 GND 6 R685 1K C546 1000P PR509 F P23 GND 3 +15V 2 +15V 1 R563 2.2 R551 330K R713 4700 R673 1K ZH81 R932 100K Q565 2SB1218AR R697 4.7 ZH83 R649 22K ZH79 Q508 HN1C01F D544 MA4200-M D517 MA4330-M R587 0.16 R596 100 R537 100K R672 1K D529 MA3X15300L R669 130K R705 1M R688 1K R682 20K D579 MA165 R698 0.16 R676 33K R653 33K R574 330 T402 MT180 C571 33P C457 0.033u Q517 HN1C01F R478 22 D528 MA3X15300L R477 180 C527 4.7 R476 180 R662 150K C577 33/100V R555 1M R571 1M IC520 LSSK0062 1 2 3 4 5 6 7 8 11 12 13 14 15 16 9 10 Q527 2SK2882 R708 1M C624 0.01 D516 MA4330-M R667 0 R931 33K R707 1M Q541 2SK3018 C620 0.01 R675 22K PR401 F 5A 250V C469 220P Q555 RSS130N03 1 2 3 4 5 6 7 8 Q409 RSR025P03 C520 0.068u C523 1.0 R570 100K ZH99 L510 EXCELDR25V T407 ETQ11K5AZ 6 5 1 4 2 R593 5600 R700 1M R702 1M R607 22K D425 MA188 R679 0.16 R562 4.7K[F] C587 3300P R568 1M T404 ETS42LA115AD P5 GNDs(W) 11 GNDs(W) 10 GNDs(S) 9 +15Vs(W) 8 +15Vs(W) 7 +15Vs(S) 6 GND 5 +15Vc 4 GND 3 +15Vc 2 +15Vc 1 C528 1.0 R629 1M D551 02DZ13 C552 0.1 C604 150u/200V R560 9.1K R680 0.16 C556 1500u/25V R582 10K Q412 2SK3683 R706 1M C451 100P R632 220 C656 2.2 D598 02DZ5.1 R660 12K C625 10 ZH80 R598 33K C526 0.022[KB] C574 0.1 R573 390 R641 47K ZH86 C643 47/50V R703 1M L514 10uH C657 1000P R645 100 R655 0.16 C605 150u/200V ZH64 R701 1M R922 100 R668 0 C655 1.0 C584 0.022 D574 MA165 R482 22 D542 MA4200-M P12 STB_PS 10 NC 9 STB_12V 8 GND 7 GND 6 GND 5 +15V 4 NC 3 Vda 2 Vda 1 C503 470P R567 1M R592 3000 R670 1000 R665 2000 R674 33K R614 3300 R696 10 D536 SF20JC6 D507 02DZ7.5 R699 1M R561 5.1K R588 390 R564 100K C650 0.1 ZH74 D572 02DZ24Z ZH94 R576 12K R651 10K C562 0.022 R952 10 R579 10K R572 390 D535 MA188 IC512 TL431A1LPM5 1 2 3 D549 02DZ24Z ZH84 D602 02DZ8.2 R585 33K C551 0.1 ZH62 D545 MA4200-M D569 02DZ24Z ZH85 J502 LSJW0001 D521 D1NS4 R704 1M C547 1000P R591 1M D530 02DZ10 R933 1K ZH66 C603 1.0 R664 9100 R613 24K R951 10 Q566 2SD1819A-RTX R584 10K D508 02DZ7.5 D571 02DZ24Z ZH75 D423 MA188 R566 1M Q564 2SB1218AR D543 02DZ15 ZH78 R545 10K D540 SF8L60 R565 1M R597 33K C534 470P R659 30K C550 330P R631 33K R650 10K R666 1000 R711 0.16 R624 10k R953 2.2K Q413 2SK3683 R633 1M D539 SF8L60 ZH82 R937 1K Q408 RSR025P03 C557 1500u/25V C601 0.01 R661 5K C555 1000u/160V R556 1M Z1 1 R635 WA5001 ZH73 D570 02DZ24Z Q520 HN1C01F ZH91 R599 390 C581 0.022 Q510 RSR015P03 Q509 HN1A01F C508 470P R690 4.7 Q556 RSS130N03 1 2 3 4 5 6 7 8 R712 4.7 R638 1K J501 LSJW0001 D538 02DZ5.1 D520 MA111 D518 MA4330-M D586 1SR153 Q538 2SK3018 C554 1.0 15 16 18 10 12 17 14 11 13 TO SS-BOARD (SS12) (SC23) TO SC-BOARD HOT COLD POWER CONTROL Vda ERROR DET(Vda) P-BOARD TNPA3911AM (2/6) COLD HOT HOT COLD Vlow PA-BOARD TO (PA5) 2 1 3 AA AB AC AD AE AF AG AH AI AJ AK AL AM AN AO AP AQ AR P-BOARD TO (4/6) AS AT 12.0 15.0 12.0 0 67.0 0 0 67.0 0 0 15.0 0 15.0 15.0 15.0 15.0 0 0 0 15.0 15.0 0 15.0 0 VLOW DET VLOW DET DC/DC CONV. DC/DC CONV. PA-BOARD TO (PA10) 14.0 0 0 0 14.0 14.0 TH-42PV65C P-Board (2 of 6) Schematic Diagram TH-42PV65C P-Board (2 of 6) Schematic Diagram 67 14.6. P 电路板 （3/6）线路图 ZH6 C630 0.01 C514 470P R921 33K C507 0.01 C414 0.047u D430 MA111 R530 33K D436 MA4200-M ZH59 R427 430K R423 1K R483 4.7M R425 33K ZH5 ZH89 ZH67 ZH44 C585 0.022 Q521 2SK3018 R407 430K R938 4.7K C517 220u C433 0.1 C654 1.0 D437 MA4200-M ZH53 IC408 ON3171 2 1 4 3 R549 10K C512 50V 470P ZH41 R413 10/5W R521 10 2.5mm R404 1K ZH68 D601 02DZ5.1 R432 1K R412 0 R594 150 2.5mm R943 1M D411 ST02D-170 C408 1000P R435 430K R539 10K R461 10K C515 1200 D438 MA4200-M IC504 TL431A1LPM5 1 2 3 T410 ETS25AF115AH 9 7 5 4 1 2 10 11 12 13 14 16 15 R418 22 ZH88 R544 330 ZH61 D412 D1NL20U C627 1000P Q537 RTR040N03 C493 47/50V C413 0.1 IC410 ON3171 2 1 4 3 R488 100K IC409 MIP2G4 Vdd 1 FB 2 CL 3 Vcc 4 DRAIN 5 6 SOURCE 7 SOURCE 8 D432 RB520 C402 1.0 IC411 TL431A1LPM5 1 2 3 R459 51K C513 50V 470P D445 MA4360-H R541 1M D596 ERA15-10 ZH45 ZH63 C516 0.47 ZN406 ERZV07D511 D511 D1NJ10 C529 1.0 Q434 2SK3302 R429 4.7 ZN405 ERZV07D511 D441 D1NL20U Q524 2SK2090 R507 220 R422 330K D404 S1WB(A)80 R416 3M R542 1K R522 10 D435 ERA15-10 C434 1.0 L410 40mH 1 2 4 3 R434 0 D563 02DZ6.2 R420 0 D416 1SR153 D444 D1NL20U ZH60 C467 220P C494 1/250V D509 D2S6M R677 470K ZH52 R540 1M D595 WA5001=5 R524 1K C497 47/50V C407 22u/450V C425 0.01 2 3 D B 4 E 8 F 1 5 6 7 A C 9 COLD HOT COLD HOT COLD HOT COLD HOT P-BOARD TNPA3911AM (3/6) ERROR DET 11 12 13 14 15 16 C J D F K B E I A H G BA BB BC BD BE BF BG BH BI BJ BK BL BM BN BO P-BOARD (1/6) TO (5/6) P-BOARD TO ERROR DET PHOTO COUPLER CONTROL DC POWER COUPLER PHOTO TH-42PV65C P-Board (3 of 6) Schematic Diagram TH-42PV65C P-Board (3 of 6) Schematic Diagram 68 14.7. P 电路板 （4/6）线路图 C632 330P R526 220K R528 4.7 R622 150K R534 47K C629 0.01 R640 0.68 ZH24 D587 MA188 D575 MA188 C653 1000P ZH27 R543 15K ZH100 Vsus R590 12K R691 100K R647 22K R550 47K Q505 2SK2998 R652 9.1K ZH112 Vsus R627 7.5K Q540 RSR025P03 ZH39 R595 2200 R589 12K ZH29 ZH23 ZH28 ZH26 T601 45H-5034A 5 9 4 6 IC509 L6565N INV 1 COMP 2 VFF 3 CS 4 ZCD 5 GND 6 GD 7 Vcc 8 P11 3 NC 2 1 C615 1400u/220V C641 1000P R620 10K C611 1400u/220V R671 10K C640 0.1 R643 0.68 PR601 T 3.15A 250V D501 S3K60 R634 0.68 R946 33K R644 0.68 R626 150K R657 1000 IC507 ON3171 2 1 4 3 R656 R947 330 R648 150K R621 12K R646 22K R527 220K C518 0.1 R612 2200 R619 0.68 IC506 HA17431 5 4 1 3 2 ZH25 P2 3 NC 2 1 C619 0.1 R628 3K R636 150K D514 02DZ6.2 R945 22K Q507 2SK3568 R639 0.68 R603 33K ZH113 GND C634 1000P Q530 2SD1819A-RTX D506 02DZ5.1 R601 47K D582 MA7056 R533 16K R654 22 ZH47 R637 0.68 ZH46 R658 1M Q525 2SK3018 R642 0.68 C531 1.0 D585 02DZ7.5 IC505 ON3171 2 1 4 3 R608 3300 R695 16K C616 1000P ZH101 GND 15 12 17 10 18 16 11 13 14 (SS11) TO SC-BOARD (SC2) TO SC-BOARD Csus ERROR DET(Vsus) Vsus P-BOARD TNPA3911AM(4/6) 16 13 12 14 11 15 AC AF AD AA AG AB AE CA CB CC CD CE CF CG CH CI CJ CK CL P-BOARD (2/6) TO P-BOARD (6/6) TO AK AL AJ AO AQ AR AM AN AI AS AH AP AT 0 0 189.0 0 0 189.0 DC-DC CONVERTER PHOTO COUPLER COUPLER PHOTO TH-42PV65C P-Board (4 of 6) Schematic Diagram TH-42PV65C P-Board (4 of 6) Schematic Diagram 69 14.8. P 电路板 （5/6）线路图 Q558 2SD1819A-RTX R616 10K C511 1000P R501 22K R615 10K D588 02DZ3.3 Q557 2SD1819A-RTX R940 1K R512 22K C505 1000P R518 1K R509 100K R504 1000 C613 0.01 R936 10K Q568 2SJ463A R684 10K R525 47K C583 1000P R935 100K IC501 M34509G4FP VDD 1 VSS 2 XIN 3 XOUT 4 CNVSS 5 Reset 6 P21 7 P20 8 D5 9 D4 10 P01 21 P00 22 D1 13 D0 14 P13 15 P12 16 P11 17 P10 18 P03 19 P02 20 D3 11 D2 12 P31 23 P30 24 C506 0.01 R520 100K R487 4.7K C659 0.01 R678 0 R532 1K Q535 2SD1819A Q554 RSR025P03 Q563 2SK2090 R535 1000 Q561 2SD1819A-RTX C639 0.01 R955 47K R502 100K R558 470K R548 1000 R586 47K Q551 2SK3018 X501 4MHz IC502 R3111N401C 1 2 5 3 4 R939 1K R519 100K C608 0.01 C510 0.1 R606 1200 C533 0.01 C607 1.0 R950 1M C509 100/25V R538 100K R617 10K C501 0.01 IC405 ON3171 2 1 4 3 R689 1000 D555 02DZ7.5 IC403 ON3171 2 1 4 3 R511 100K R956 100K C519 1.0 R575 1000 R516 1000 R618 100K IC401 ON3171 2 1 4 3 R536 1000 R503 100K R505 33 IC412 ON3171 2 1 4 3 R580 47K R578 47K IC404 ON3171 2 1 4 3 R557 100K R517 10K R510 100K C502 0.01 R686 1000 R611 47K R554 1000 C638 0.01 Q559 2SD1819A-RTX C610 1.0 R514 100K R581 47K R687 10K R515 1000 Q512 2SK3018 D505 D1NS4 R714 100 C504 1.0 R610 47K D512 MA111 R583 47K Q553 2SD1819A-RTX R552 10K C626 0.01 Q502 2SD1820A R602 3300 D513 MA111 D559 02DZ7.5 R715 100 R546 1000 C612 0.01 R508 1000 Q569 2SK3018 Q501 2SD1820A C631 0.01 R683 33K R577 47K R609 1000 D590 02DZ3.3 R630 4.7K D515 02DZ3.3 R513 100K R506 1000 7 8 A C 9 3 2 D B 4 5 E 6 F 1 COLD HOT COLD HOT HOT COLD POWER MCU RESET P-BOARD TNPA3911AM (5/6) 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 BO BG BK BE BD BN BM BL BB BI BH BA BJ BF BC P-BOARD TO (3/6) COUPLER PHOTO COUPLER PHOTO COUPLER PHOTO COUPLER PHOTO PHOTO COUPLER TH-42PV65C P-Board (5 of 6) Schematic Diagram TH-42PV65C P-Board (5 of 6) Schematic Diagram 70 14.9. P 电路板 （6/6）线路图 P25 ALL_OFF 18 Panel_Main_ON 17 PS_SOS 16 ECO_ON 15 FAN_SOS 14 F_STBY_ON 13 GND(STBY) 12 GND 11 STBY5V 10 +5Vc 9 GND 8 +5Vc 7 GND 6 GND 5 GND 4 NC 3 +15Vc 2 +15Vc 1 AC_GOOD 19 KILL_SOS 20 R553 100 L512 4.7uH C658 1.0 R569 33K R547 100 D599 D1FP3 C661 0.01 R529 100 C558 470u/25V L511 47uH D502 WA5001=5 R523 47K C559 1200 C623 10 C660 2.2 IC510 BD9703FP 1 2 3 4 5 D600 02DZ7.5 R559 8.2K PR505 TF16N5.00 C662 0.01 15 12 17 10 16 13 18 11 14 P-BOARD TNPA3911AM (6/6) (D25) D-BOARD TO 42 41 32 45 46 36 34 39 38 40 33 37 43 31 44 35 CG CK CL CB CA CE CF CI CC CD CJ CH (4/6) TO P-BOARD 0 5.0 2.6 0 5.0 5.0 0 0 0 0 0 15.0 0 3.2 0 0 15.0 0 0 0 REGULATOR SWITCHING TH-42PV65C P-Board (6 of 6) Schematic Diagram TH-42PV65C P-Board (6 of 6) Schematic Diagram 71 14.10.PA 电路板方框图 ON/OFF D5644 D5635 D5639 D5641 D5637 D5643 D5647 D5642 D5638 D5649 D5804 MAIN9V TP16 TPS9V TPS9 TPS5 TPS5V TPM5 TPM5V D2309 D5640 TPS33 TPS33V TPM33 TPM33V TPM18V TPM18 TPM9V TPM9 TP5616 TP5615 TP5617 D5634 D5805 D5806 D5807 MAIN9V D5646 6 SUB_5V Q5603 7 22 Q5602 SUB_9V-1 SUB9V PA_SOS 3 FAN_SOS F_STBY_14V 23 8 20 MAIN_5V SUB5V PA20 9 LINP 1 21 IC2306 19 W_L+ SUB_3.3V 35 W_R+ LOUTP 5 W_R- 1 LOUTN LOUTP SHUTDOWN IC2304 34 MAIN_9V(0.4A) PA2 8 SUB9V(2.2A) 26 SOUND_SOS TUNER_SUB_ON ON/OFF1 24 TUNER_MAIN_ON 3 16 3 SUB9V Q5643 SUB9V 1 SUB5V MAIN9V VOUT1 MAIN3.3V F_STBY_14V 1 TO P10 MAIN1.8V Q2306 6 NR14V 6 ROUTP RINP 1 5 27 7 OP AMP 39 VOUT1 VIN FAULT IC5601 5 PVCCR ROUTN MAIN3.3V AVR 5V/9V 13 48 40 ON/OFF1 2 2 42 ON/OFF2 9 TO SPEAKER 2 VIN Q5641 5 41 10 3 +15V VOUT2 OP AMP 14 2 4 MAIN3.3V 19 16 VOUT2 3 MAIN9V FAN_CONT PA40 6 STB5V 12 18 Q5601 MAIN1.8V MAIN5V ON/OFF2 ON/OFF 37 17 35 39 2 Q5605 MAIN5V 1 Q5644 +15V SR W_L- 7 SUB9V 32 AVCC 4 ROUTN PVCCL 15 5 IC5602 ROUTP SUB5VA PVCCL AMUTE SL 3 13 MAIN_1.8V 20 LOUTN 2 IC2302 7 46 1 44 3 MAIN_9V 33 PA5 Q2302 (W-R & W-L) F_STBY_14V PVCCR 2 34 +15V PA10 AVR 1.8V/3.3V +15V +15V FAN 3 PA32 SOS 3 FAN 1 PA33 FAN 1 FAN SOS 1 PA34 SOS 3 1 SOS PA31 3 AVR 15V Vin ON/OFF 5 1 IC5801 Q2307 SUB5VA TO P5 Q5642 PA SUB5V/MAIN5V SUB9V/ MAIN9V Q5613 STB5V1 STB5V1 TO H40 Q5604 ON/OFF TV_SUB_ON IC5604 VIN 5 AVR 3.3V VOUT 1 TO DG20 MAIN_9V(0.1A) SUB5V(1.0A) MAIN5V(0.37A) MAIN5V TUNER_MAIN_ON SPEAKER AMP Q2300 Q2301 11 SUB3.3V 13 MAIN3.3V SUB3.3V MAIN3.3V(1.55A) MAIN1.8V(1.2A) MAIN3.3V(2.5A) SUB9V(1.7A) MAIN1.8V(1.2A) SOS Vout 2 4 Vadj Q2303 15 Q5610 9 1 (sw) FAN CONTROL SPEAKER OUT/AUDIO AMP FAN CONTROL DC-DC CONVERTER LED BLINKING : 12TIMES SOUND SOS FAN SOS LED BLINKING : 11TIMES PA SOS LED BLINKING : 10TIMES TH-42PV65C PA-Board Block Diagram TH-42PV65C PA-Board Block Diagram 72 14.11.PA 电路板 （1/3）线路图 + + + + + + STB_5V 4.4V SUB_9V SUB_9V MAIN_1.8V MAIN_9V NR14V R5808 2.2k D5807 MA2J11100L R5648 3.9k R5802 13k D5634 MA2J11100L R5806 2.2k C5643 16V 0.1u L5606 22u L5622 G1C150MA0234 C5670 25V 0.1u R5644 2.2k R5627 4.7k R5650 220 R5672 10k Q5643 2SA207700L C5805 1u 16V R5805 2.2k R5641 2.2k R5836 1k C5641 16V 0.1u L5604 2.7u R5626 4.7k 1 2 3 R5634 470 R5639 2.2k R5694 47k R5695 10k D5649 MA2J11100L D5646 MA3X152E0L C5609 50V 22u R5693 33k R5633 1k Q5602 B1ABCF000138 R5662 4.7k C5637 16V 0.1u R5605 4.7k R5645 2.2k R5642 470 1 2 3 4 5 6 C5801 470u 25V L5602 2.7u R5660 0 R5646 4.7k R5692 1k R5649 100k L5801 G0C101K00023 C5642 16V 0.1u D5642 MAZ31200ML D5801 B0JCME000037 R5632 470 C5802 470u 25V C5804 0.1u 16V C5809 1u 25V R5659 470 R5822 100 R5804 TP16 D5639 MAZ30470HL R5826 100 R5609 200 Q5613 B1ABCF000138 R5637 10k R5665 47k D5643 MA3X152D0L D5638 MA3X152E0L Q5601 B1DHDC000028 R5640 4.7k Q5604 B1ABCF000138 R5606 2.2k L5624 G1C330MA0234 C5605 25V 470u R5625 4.7k R5824 100 D5635 MAZ30470HL R5621 4.7k D5606 B0BC01100001 R5801 845 R5823 100 C0DBAZF00003 IC5801 1 Vin 2 Vout(sw) 3 GND 4 Vadj 5 ON/OFF R5809 4.7k R5647 220 R5807 2.2k R5667 47k R5664 4.7k R5803 2k D5805 MA3X152E0L C5619 25V 0.1u R5643 1k 1 2 3 1 2 3 Q5642 2SA207700L R5638 10k C5644 16V 0.1u L5802 100u D5804 MAZ31200ML D5640 MAZ30390HL D5641 MA3X152D0L Q5644 B1ABCF000138 D5647 MA3X152D0L D5806 MA3X152E0L R5654 10k 1 2 3 R5635 220 D5644 MAZ30680ML Q5641 2SA207700L R5601 180 C5606 16V 470u C5810 47u 25V D5637 MA3X152E0L N0BG2DE00001 IC5601 1 N.C. 2 ON/OFF2 3 VAR2 4 VOUT2 5 SW-Node2 7 GND 8 N.C. 9 GND 10 VIN 11 N.C. 12 GND 13 SW-Node1 14 VOUT1 15 VAR1 16 ON/OFF1 < F_STBY_14V F_STBY_14V NR14V GND MAIN_9V SUB_5V SUB_9V-1 GND MAIN_5V SUB_9V TO FAN SUB_3.3V GND F_STBY_14V 1 6 D E 8 B 3 2 C 4 A 7 5 MAIN3.3V SUB_5V SUB_3.3V NR14V MAIN3.3V MAIN1.8V MAIN_5V 15V 15V PA_SOS PA 31 PA 32 PA 33 PA 34 PA 10 SUB_5V FAN_SOS TO P-BOARD (P10) AVR 5V/9V FAN SOS AVR 15V FAN CONTROL MAIN_9V MAIN_5V MAIN_1.8V STB_5V 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 14.0 14.0 0 14.0 0 0 PA-BOARD TNPA3761AD (1/3) TH-42PV65C PA-Board (1 of 3) Schematic Diagram TH-42PV65C PA-Board (1 of 3) Schematic Diagram 73 14.12.PA 电路板 （2/3）线路图 + + + + + + + + SOUND_SOS SOS SUB5V SUB_3.3V SUB_3.3V ODU_17V NR14V TV_SUB_ON TV_MAIN_ON MAIN_1.8V TPSTB5V TPM5V TPS33V C5646 50V 0.01u C5623 25V 0.1u D5610 B0BC4R700007 R5669 47k JS2303 0 JS2300 0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 JS2302 0 TPM33V Q5605 B1ABCF000138 TPFSOS C5613 25V 0.1u TPS5V R5620 1k TPS9 R5619 33k TPSSOS D5607 B0BC6R600005 MAIN5V L5651 22u R5603 15.4k JS2319 0 L5612 2.7u Q5610 B1ABCF000138 TPMUTE R5615 10k L5621 G1C330MA0234 C5626 16V 0.1u TPM18 C0DBZGC00067 IC5604 1 VIN 2 GND 3 STBY 5 VOUT 4 NC R5668 47k TPM33 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 R5617 1k C5611 50V 330u TPM18V L5609 22u Q5603 B1DHDC000028 R5607 4.53k R5676 10k L5607 22u C5673 16V 0.1u C5647 16V 47u JS2331 0 TPM9 R5652 0 TPS33 L5623 G1C150MA0234 TP17V SUB3.3V C5672 50V 22u R5653 10k C5645 16V 47u C5617 16V 470u TPM5 MAIN3.3V TPM9V C5618 25V 0.1u JS2301 0 TPS9V C5633 25V 220u EHMDD9851 IC5602 1 ON/OFF2 2 VAR2 3 VOUT2 4 SW-Node2 6 GND 7 N.C. 8 GND 9 VIN 10 N.C. 11 GND 12 SW-Node1 13 VOUT1 14 VAR1 15 ON/OFF1 16 N.C. MAIN9V C5616 25V 0.1u C5648 50V 0.01u C5622 16V 470u SUB9V C5612 16V 470u TPS5 L5615 15u D5612 B0BC3R700006 MAIN3.3V SUB3.3V MAIN9V SUB5VA SUB9V TP5617 TP5615 TP5616 MAIN1.8V SUB5V(0.63A) SUB9V(1.3A/0.766A) Tuner_Main_ON SUB_9V(1.7A) MAIN5V(0.37A/0.46A) ODU +B 17.5V / 0.27A TUNER_SUB_ON MAIN3.3V(1.55A/1.847A) PA_SOS SCL1(Main3.3V) SDA1(Main3.3V) MAIN_3.3V(1.55A) ODU_ON/OFF MAIN1.8V SUB9V(1.3A/0.766A) MAIN3.3V(1.55A/1.847A) MAIN_5V MAIN_3.3V SUB_5V MAIN_5V(0.37A) HP_R HP_L GND SUB_5V(1.0A) FAN_CONT FAN_SOS MAIN_1.8V (1.2A) MAIN_9V(0.1A) AMUTE HP_MUTE SOUND_SOS MAIN9V(0.1A/NC) MAIN1.8V SR SL 8 12 11 15 13 10 14 9 SUB9V(1.3A/0.766A) SUB5V(0.63A) MAIN5V(0.37A/0.46A) MAIN3.3V(1.55A/1.847A) SUB_5V SUB_9V MAIN_5V SUB_3.3V MAIN_9V MAIN3.3V 15V 15V PA 20 PA 40 SUB_5V H-BOARD TO (H40) TO DG-BOARD (DG20) AVR 1.8V/3.3V STB_5V STB_5V 15V 5 1 4 7 13 8 10 15 3 2 16 11 12 14 6 9 31 32 33 34 35 PA-BOARD TNPA3761AD (2/3) SUB5VA SUB5VA SUB5VA SUB5VA TH-42PV65C PA-Board (2 of 3) Schematic Diagram TH-42PV65C PA-Board (2 of 3) Schematic Diagram AVR 3.3V 74 14.13.PA 电路板 （3/3）线路图 + + + + Thermal Pad MAIN_9V +15V MAIN_9V Q2301 B1ABCF000138 R2406 4.7k R2357 0 C2322 1u 10V C2336 0.47u 50V R2407 1.24k C2333 25V 470u R2341 0 L2302 G0C330MA0049 R2422 787 R2421 1.62k R2397 0 R2404 330 R2311 1.3k 1% C2320 1u 10V C2331 1u 25V C2387 1u 10V C2380 50V 0.01u C2334 0.1u 25V R2323 0 D2309 MA2J11100L R2325 10k R2312 10k C2374 10V 1u R2384 1.15k C2328 1u 25V R2398 0 R2332 10k Q2303 B1ABCF000138 C2324 0.22u 25V R2410 787 R2364 47k R2408 1.07k C2385 1u 10V C2402 10u 6.3V C2335 0.1u 25V C2330 1u 25V R2363 470 C2321 0.01u 50V C2325 0.1u 25V C2417 10u 6.3V C2373 50V 0.1u R2375 100 C2326 0.1u 25V C2327 0.47u 50V R2366 4.7k 2SA207700L Q2306 C2338 0.22u 25V ZA2300 K4CZ01000027 R2372 680 R2405 330 C2382 1u 16V IC2306 C0ABBA000168 1 2 3 4 5 6 7 8 C2394 1u 16V C2317 1u 10V R2349 100 R2373 680 R2402 330 C2301 25V 470u R2368 0 C2314 1u 16V L2301 G0C330MA0049 2SA207700L Q2307 R2361 5.6k R2329 100k PA5 1 2 3 4 5 6 7 8 9 10 11 ZA2301 K4CZ01000027 R2360 10k R2409 1.62k MAIN9V R2388 3.3k L2300 G0C330MA0049 Q2302 B1ABCF000138 C2393 1u 16V R2376 10k C2323 0.22u 25V C2332 25V 470u R2387 1.15k C2401 1u 10V C2342 1u 25V R2403 4.7k PA2 1 2 3 4 5 C2329 1u 25V R2383 3.3k R2369 18k R2324 0 L2303 G0C330MA0049 IC2304 C0ABBA000168 1 2 3 4 5 6 7 8 R2401 330 C2303 16V 100u L2308 3.9u R2310 1.3k 1% Q2300 2SA207700L C1AB00002451 IC2302 1 NC 2 RINN 3 RINP 4 AGND 5 LINP 6 LINN 7 NC 8 GAIN0 9 GAIN1 10 MSTR/NSLV 11 SYNC 12 NC 13 NC 14 ROSC 15 VREG 16 VBYP 17 AGND 18 BSLP 19 LOUTP 20 LOUTP 21 LOUTN 22 LOUTN 23 BSLN 24 NC 25 NC 26 PVCCL 27 PVCCL 28 PGNDL 29 PGNDL 30 VCLAMPL 31 VCLAMPR 32 PGNDR 33 PGNDR 34 PVCCR 35 PVCCR 36 NC 37 NC 38 BSRN 39 ROUTN 40 ROUTN 41 ROUTP 42 ROUTP 43 BSRP 44 NSHUTDOWN 45 MUTE 46 FAULT 47 NC 48 AVCC C2337 0.22u 25V R2359 2.2k R2365 100 C2341 10u 25V C2403 50V 0.01u R2379 2.2k R2380 2.2k MAIN9V - GND W_L VCC TO WOOFER/SPEAKER 15V GND (W-R & W-L) +15V +15V GND GNDs GNDs R GNDs +15V W_R+ +15V W_R W_R- W-L NC W_L+ W-R W_L- + L +15V - + + L R - - + GND VCC SOUND_SOS 23 22 18 19 17 21 16 20 15V TO P-BOARD (P5) OP AMP OP AMP SPEAKER AMP 34 31 33 35 32 15.0 0 0 0 0 15.0 0 15.0 15.0 15.0 15.0 PA-BOARD TNPA3761AD (3/3) TH-42PV65C PA-Board (3 of 3) Schematic Diagram TH-42PV65C PA-Board (3 of 3) Schematic Diagram JS5602 AB AC AD AE AF SUFFIX 75 14.14.H 和 TA 电路板方框图 TH-42PV65C H and TA-Board Block Diagram TH-42PV65C H and TA-Board Block Diagram 10 TUNER AFT1 TA6 VIDEO_OUT 8 6 TUNER 17 TA TU001 12 SIF 11 11 15 S-CLOCK 14 RF AGC AFT SIF1(MSP) 2 S-DATA MAIN VIDEO RFAGC1 TA5 1 9 8 8 SCL0B SDA0B SUB 30V 15 BTL SUB 5V SUB 5V SDA0B SCL0B BT30V Q002 6 8 6 11 15 2 H5 1 9 8 H AV1_C AV_R A AV2C_Y V2_V AV2C_YSW AUDIO_LIN AUDIO_RIN PC_LIN PC_RIN TV_L TV_R AV1_L AV1_R AV2_L AV2_R AV3_L AV2C_Y AV2C_PB AV2C_PR AV3C_PB AV3C_Y RM_IN PC_B PC_G PC_R PC_V PC_H AV3C_YSW AV3C_Y AV3C_PB AV3C_PR AV3_V AV3_L AV3_R AV2C_YSW AV2C_Y AV2C_PB AV2C_PR AV2_V AV2_L AV2_R AV1_C AV1_Y AV1_S AV1_V AV1_L AV1_R AV3C_YSW AV3C_Y AV3_V HDMI_SL HDMI_SR AV3_R AV4_R AV4_L AV_L AV_R AV4_Y AV4_V AV4_S HP_ROUT HP_LOUT AI_SENSOR AV4_R AV4_L AV4_Y AV4_V AV4_C AV4_S RM_IN STBY_LED AI_SENSOR STBY_LED KEY1 PC_V PC_H PC_R PC_B PC_G HDMI_SL HDMI_SR AV_L AV4_C AV3C_PR KEY_EDGE KEY1 KEY_EDGE TV_L TV_R HP_LOUT HP_ROUT 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 MAIN PB/COUT1 IN IC3005 AV2 IN AV1 56 48 VIDEO SW 52 SA1 49 OUT PROUT1 50 Y/VOUT1 58 Y2 S-2 V2 59 4 3 8 Y4 PDD1 V4 36 SC1OR 27 24 57 SC1IL 25 56 SC1OL MSP 37 SC1IR 28 IC2106 + 7 Q2104 1 Q2105 3 5 - - + IC2104 VAO SC2OR 33 34 SC2OL L R Q2103 Q2102 Q2002 Q2001 Q3017 Q3011 38 VOUT4 TV OUT H 67 SCL 36 SDA 35 SDA0B SCL0B MAIN PB MAIN PR 16 18 RM_IN AFC1 13 8 V7 14 AUDIO_L AUDIO_R Q2106,Q2108 16 17 1 2 3 4 8 9 32 33 L8 R8 L7 R7 L1 R1 L2 R2 L4 R4 PC IN TV IN AV1 IN AV2 IN AV3 IN MAIN ROUT1 LOUT1 OUT SDA SCL 35 36 IC2105 AUDIO SW SDA0B SCL0B 60 19 CY1 PR1 PB1 20 17 PR2 24 22 PB2 CY2 25 AV3 IN AV2 RGB IN RGB IN AV3 VOUT5 42 14 Q3014 MAIN Y/CVBS Q3015 MAIN CVBS 20 STBY_LED 6 TO G51 H51 7 STBY_LED KEY1 RM_IN 9 14 JK2003 AUDIO IN H15 1 AGC1 TV IN AI_SENSOR 4 TO DG1 H1 C1 JK3001 PC IN Q3333 Q3332 Q3331 PC_R PC_G PC_B 5 IC3301 3 6 2 SIF TRAP 11 10 L5 R5 HDMI IN 7 6 L3 R3 AV4 IN C3 64 63 Y3 V3 1 IN AV4 2 S-3 Q2012 Q2011 Q2013 STB5V 19 MAIN_R 17 AV4_C AV4_S AV4_Y 25 AV4_V 22 29 AV4_L 27 20 18 AV4_R AI_SENSOR 10 HDMI_SR 52 HDMI_SL 54 PC_H 34 30 PC_G 36 PC_B 32 PC_V PC_R 38 Q3028 62 SA3 STB 5V 6 SUB 5V 8 STB 5V SUB 5V MAIN_L KEY_EDGE 10 TO DG2 H2 KEY1 9 KEY_EDGE 12 14 15 72 XOUT 71 X2101 XIN SOS 80 77 RESET 74 AUDIO MUTE SP MUTE 1 SUB 3.3V 73 STB 3.3V SUB 3.3V STB 3.3V SL 3 SL 4 SR 7 SR 8 IN2 IN1 5 3 MUTE 2 OUT2 OUT1 7 1 IC2109 HP AMP Q2315 Q2302 Q2300 MUTE CCT MUTE CCT MUTE SW V DET Q2317 75 STB 5V Q2316 Q2301 Q2314 Q3008 SOS SCL 2 3 SDA SDA0B SCL0B 21 RESETQ Q2113 Q2114 SDA0B SCL0B SDA0B 66 SCL0B 65 76 MSP_RESET TO PA40 H40 1 STB 5V 7 SUB 5V 9 SUB 5V 3 SUB 9V MAIN 9V 5 11 SUB 3.3V MAIN 3.3V 13 A_MUTE 15 MAIN 3.3V SUB 9V SUB 5V SUB 3.3V MAIN 9V STB 5V SUB 8V SUB 5V BT30V DACM L PROCESSING SELECT PRE- MODULATOR ANA IN+ SP OUT OUT SELECT OUT HEADPHONE PROCESSING PROCESSING DACA R DACM R LOUDSPEAKER SELECT SOUND OUTPUT DACA L ADC DE- AUDIO SOUND DSP PRESCALE INPUT DAC SOURCE DAC IN MAIN OUT DAC TV HP SURROUND ADC AV TERMINAL/AV SWITCH/MSP 8 VCC 1 3 IN AVR 5V IC2110 MAIN 9V OUT A MUTE BUFFER LED BLINKING : 10TIMES TUNER SOS AV1_S 55 S-1 AV1_Y 54 Y1 AV1_V 53 V1 PR PB Y PR AV2 V L C R R L Y R L V R V V AV1 L MONITOR OUT PB Y JK3100 TJB0A639 Y-SW Y G PB PR V L R-SW R G Y-SW Y G PB PR V L R-SW R G C Y G Y-G C-G G V L R-SW R G V L R G AV3 76 14.15.H 电路板 （1/3）线路图 3 9 7 A 8 6 E C D B 1 F 4 5 2 1 2 3 4 5 6 7 8 9 10 ! + + + PR PB Y PR AV2 V L C R R L Y R L V AV4 R V V AV1 L MONITOR OUT PB Y + NP RED WHITE + + + + NP + + + NP R3307 4.7k R3306 4.7k RST PC_R GUARD_SR GUARD_SL AUDIO_MUTE PC_B PC_GND_R PC_GND_G PC_RIN GUARD_SL HP_LOUT 3.3V_MAIN PC_H GUARD_SL GUARD_SL GUARD_SR HP_ROUT PC_G PC_V GUARD_SR GUARD_SR SP_MUTE PC_GND_B AUDIO_MUTE 9V_PC 9V_PC A_AV3_L A_AV2_L A_AV1_L AV3_R AV2C_Y A_AV2_R AV2C_YSW A_AV1_RSW AV3_L AV3_V AV1_R A_LOUT A_AV3_L AV3C_PR AV1_V A_ROUT A_AV3_R AV3C_PB AV3C_YSW A_AV1_L AV3C_Y A_AV2_L A_AV1_R A_AV3_RSW AV1_S A_AV2_RSW A_AV2_R AV1_Y AV2_V AV1_L A_LOUT A_AV3_R AV1_C AV2_R A_AV3_RSW AV2C_PR A_AV2_RSW A_AV1_R AV2_L A_AV1_RSW AV2C_PB A_ROUT A_AV1_V A_VOUT VOUT4 AUDIOOUT_L AUDIOOUT_R PC_LIN D3047 MAZ81400ML Q3331 2SC24800VL JS3011 0 C2011 50V 560p JS2022 D3046 MAZ81400ML C2236 16V 47u R3338 100 JS3310 0 L2016 J0JCC0000100 D3042 MAZ81400ML Q2001 B1ABDF000034 R2203 100 D3338 MA2J11100L R3323 0 2.0 x 1.25 CL019 R3324 0 2.0 x 1.25 SUB5V C2017 50V 560p 1% R3001 75 R3344 100 1% R3318 75 C2010 50V 560p R3350 51 D3043 MAZ81400ML C3340 50V 0.1u R3349 68 C2013 50V 560p C2232 1u 6.3V FL3303 J0HABB000004 1 2 3 4 Q2002 B1ABDF000034 C2021 560p 50V R3346 47k 2.0 x 1.25 R3342 18k Q2300 B1ABDF000034 B1ABCF000138 2SC584500L 2SD0601A0L C3005 50V 0.1u 1% R3313 75 Q3002 2SA207700L C2019 16V 220u 1% R3008 75 R2049 10k C0JBAZ002205 IC3301 1 /1OE 2 1A 3 2Y 4 GND 5 2A 6 1Y 7 2OE 8 Vcc L2012 J0JCC0000100 C3069 25V 470u D2301 MA2J11100L C3339 16V 0.1u R3011 0 ERJ3GEY0R00V R2219 100 R2302 22k JS2031 JS3014 0 ERJ6GEY0R00V JS3015 0 ERJ6GEY0R00V R3317 10k L2004 J0JCC0000100 CL215 D2300 MA2J11100L R3320 0 2.0 x 1.25 L2002 J0JCC0000364 JS3309 0 R2046 10k JK3100 TJB0A639 Y-SW Y G PB PR V L R-SW R G Y-SW Y G PB PR V L R-SW R G C Y G Y-G C-G G V L R-SW R G V L R G D3017 MAZ81400ML R3351 51 IC2109 C1BB00000947 BH3544F-E2 1 OUT1 2 MUTE 3 IN1 4 GND 5 IN2 6 BIAS 7 OUT2 8 VCC R2338 0 R2016 330 FL3301 J0HABB000003 1 2 3 4 JK3001 K1FB315A0005 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 C2227 16V 100u SUB9V_VIDEO L2008 J0JCC0000100 R2010 22k 1% R3027 75 C3335 16V 0.1u C3331 50V 0.01u Q3333 2SC24800VL 1% R3002 75 R3341 47k JS3010 0 ERJ6GEY0R00V C3060 16V 1u 1% R3004 75 C3334 47u 16V JK2003 K2HA204A0038 C2235 1u 6.3V R2013 2.2k C2231 47u 16V STB+5V STB+5V R3347 470 C2228 50V 0.01u C2243 16V 47u R3343 470 D2014 MA2J11100L R2043 47k C3330 16V 47u D3003 MAZ81400ML D3100 MAZ81400ML CL020 D3335 MA2J11100L 1% R3006 75 1% R3010 75 R2011 22k R2304 100k R2054 10k AN7705SP-E1 IC2110 OUT 3 2 COMMON IN 1 R2014 2.2k R2305 470 C2230 16V 100u JS3012 0 R2230 100k R2005 100k R2012 100k MAIN9V R3352 51 R3345 18k R2227 0 D3048 MAZ81400ML D2303 MA2J11100L R3305 100 JS3307 0 CL214 1% R3020 22k R3408 360 JS2021 R2233 15k C3338 47u 16V D2013 MA2J11100L L2015 J0JCC0000100 L3001 J0JCC0000100 C3332 50V 0.1u D3049 MAZ81400ML R2232 15k R2050 10k R3308 0 STB+5V L3013 J0JCC0000100 D3006 MAZ81400ML C3305 16V 0.1u R2006 22k FL3304 J0HABB000004 1 2 3 4 D3339 MA2J11100L D3041 MAZ81400ML Q2302 B1ABDF000034 C2014 50V 560p L2003 J0JCC0000100 D3039 MAZ81400ML D3038 MAZ81400ML JS3308 0 JS2032 C2307 16V 100u R3302 100 C2234 50V 1000p C3337 16V 0.1u R2306 820 R3336 47k R2042 1M D3045 MAZ81400ML D3334 MA2J11100L FL3302 J0HABB000003 1 2 3 4 Q2301 2SD0601ASL C2020 50V 22u R2051 180k D2304 MA2J11100L C2430 10V 1u R3340 100 R3309 0 R2048 470 R2310 180k C3341 50V 0.1u JS3013 0 ERJ6GEY0R00V R2009 22k Q2013 2SA207700L R3409 360 L2001 J0JCC0000364 MAIN9V R3039 220 C3342 50V 0.1u R2303 5.6k R2007 22k 1% R3310 75 MAIN9V_PC R3337 18k R2045 10k R2044 1k R2307 100k R3134 100k R2015 330 D3040 MAZ81400ML L3003 J0JCC0000100 R3022 10k JS3311 0 D2011 MA2J11100L R2052 180k 1% R3003 75 R3312 10k R3021 10k 1% R3005 75 D2012 MA2J11100L R3339 470 1% R3009 75 C2217 1u 6.3V C2022 560p 50V R2220 15k L3010 J0JCC0000100 R2311 1.8k D3005 MAZ81400ML L2011 J0JCC0000100 R2053 470 R2400 1.8k Q2011 2SA207700L C2016 50V 560p R3330 0 ERJ3GEY0R00V R2008 22k R2231 100k C2233 50V 1000p C2229 16V 100u D3336 MA2J11100L C2006 50V 560p JS3312 0 C2005 50V 560p L2007 J0JCC0000100 Q2012 B1ABDF000034 D3337 MA2J11100L R2354 1k Q3332 2SC24800VL R3348 68 1% R3012 75 MAIN3.3V FL3305 J0HABB000004 1 2 3 4 C3336 47u 16V 1% R3007 75 L3002 J0JCC0000100 JS2033 VIDEO/2 HP AMP Rin Lin MAIN9V B VD HD R G STB5V MUTE CCT. AV3 H-BOARD TNPA3760AD (1/3) TH-42PV65C H-Board (1 of 3) Schematic Diagram TH-42PV65C H-Board (1 of 3) Schematic Diagram 77 14.16.H 电路板 （2/3）线路图 12 18 16 17 15 10 13 14 11 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 ! + + + + NP + + + + + + NP + + GUARD_A TV_L SUB9V AV1_R SDA0B TV_R AV2C_YSW VOUT3 AV4_R AV2_R SDA0B VOUT5 AV3C_YSW SCL0B AV4_Y SD_AUDIO_GND AV4_VGND AV4_V SUB_PR_OUT HDMI_SL AV4_S AV2_L SCL0B SUB_PB_OUT MAIN_RF_CVBS HDMI_SR AV4_C TV_L SUB_Y_OUT SL_GND AV_L AV2C_Y SD_AUDIO_GND SR_GND MAIN_PR_OUT AV_R AV1_V GUARD_A MAIN_Y_OUT AV4_YGND AV4_CGND AV4_CGND MAIN_PB_OUT AV3_R AV1_S MSP_RESET AV3_L VOUT4 AV1_L PC_RIN AV4_L PC_LIN TV_R 5.00V MSP AUDIOOUT_L AUDIOOUT_R MAIN_L MAIN_R AV3C_Y AV2C_Y AV2C_PR AV1_Y AV1_C SUB_RF_CVBS SDA0B SCL0B AV2C_PB AV3C_PB AV3C_PR AV2_V AV3C_Y AV3_V MAIN_RF_GND SUB_RF_GND SUB5V_MSP SR SL AV_R AV_L AMUTE STB+5V R2188 10k C2177 50V 0.01u C2165 16V 1u C2169 16V 1u C2200 50V 47p L2112 J0JCC0000241 C2240 50V 0.01u R3059 220 C3029 16V 1u R3064 220 C2201 50V 3p R2184 220 R2172 220 R2170 220 C3053 50V 0.01u R3100 220 C3046 50V 0.01u R3095 220 R2214 3.3k C2192 16V 10u C3065 50V 0.01u C2238 50V 0.01u C2163 16V 1u SUB5V 1% R3233 75 C2189 16V 1u C3058 25V 470u C2196 50V 0.1u Q2108 B1ABDF000034 JS2108 C2199 50V 56p JS2026 R2152 22 C2150 16V 1u R2181 0 C2195 50V47p C2134 50V 47p C2164 16V 1u R2132 33k R3113 0 C2152 16V 1u C3040 16V 0.1u 1% R2138 10k L3026 J0JCC0000100 IC2106 C1AB00002468 1 NC 2 I2C_CL 3 I2C_DA 4 I2S_CL 5 I2S_WS 6 I2S_DA_OUT 7 I2S_DA_IN1 8 I2S_DEL_IN 9 I2S_DEL_OUT 10 I2S_DEL_CL 11 I2S_DEL_WS 12 DVSUP 13 DVSUP 14 DVSS 15 DVSS 16 DVSS 17 IS2_DA_IN2 18 NC 19 I2S_CL3 20 I2S_WS3 21 RESETQ 22 I2S_DA_IN3 23 I2S_DA_IN4 24 DACA_R 25 DACA_L 26 VREF2 27 DACM_R 28 DACM_L 29 DACM_C 30 DACM_SUB 31 DACM_SR 32 DACM_SL 33 SC2_OUT_R 34 SC2_OUT_L 35 VREF1 36 SC1_OUT_R 37 SC1_OUT_L 38 CAPL_A 39 AHVSUP 40 CAPL_M 41 SC3_OUT_R 42 SC3_OUT_L 43 AHVSS 44 AHVSS 45 AGNDC 46 NC 47 SC4_IN_L 48 SC4_IN_R 49 ASG 50 SC3_IN_L 51 SC3_IN_R 52 ASG 53 SC2_IN_L 54 SC2_IN_R 55 ASG 56 SC1_IN_L 57 SC1_IN_R 58 VREFTOP 59 SC5_IN_L 60 SC5_IN_R 61 AVSS 62 AVSS 63 NC 64 NC 65 AVSUP 66 AVSUP 67 ANA_IN1+ 68 ANA_IN- 69 ANA_IN2+ 70 TESTEN 71 XTAL_IN 72 XTAL_OUT 73 TP 74 AUD_CL_OUT 75 NC 76 SPDIF_OUT 77 D_CTR_I/O_1 78 D_CTR_I/O_0 79 ADR_SEL 80 STANDBYQ C2130 10V 1u R3073 220 C2141 50V 0.01u R3111 0 C2147 50V 22u Q2113 B1ABDF000034 SUB8V Q2114 B1ABDF000034 R3222 0 C2179 16V 10u R2158 220 C2139 50V 0.01u R2156 220 R2127 4.7k R3094 220 R2239 0 R2185 220 R3070 1k L2179 J0JCC0000241 Q2104 2SA207700L C2191 50V 0.1u C2173 50V 0.01u R3096 0 R2204 560 R2162 220 R3167 1k R3060 220 C2154 50V 0.1u R3112 0 R2195 100k C3048 50V 0.01u C2125 50V 1000p C2111 50V 0.1u ZA2106 TESA169 R2168 4.7k 1% R2131 8.2k R3090 22 SUB5V C2184 50V 0.1u JS3023 SUB5V C3056 10V 1u C2223 50V 39p X2101 H0J184500027 L2111 J0JCC0000241 R2211 0 C2237 50V 0.01u 1% R2130 10k R2177 220 C2222 50V 0.1u C3038 16V 0.1u ZA2108 TESA169 C2226 50V 1000p C3049 10V 1u R3061 0 C3031 10V 1u C2172 50V 1000p SUB9V R2393 10k R2133 0 R2392 22k C2155 16V 1u C2119 16V 47u ZA2101 TESA169 R2114 0 ERJ3GEY0R00V C2211 16V 0.1u C3033 10V 1u 1% R2147 10k C2127 16V 100u L2182 J0JCC0000241 C2225 16V 1u L2205 J0JCC0000241 L2178 J0JCC0000241 SUB8V Q2103 2SA207700L R3068 75 1% L2117 G0C6R8K00002 Q2105 2SA207700L R2193 220 C2198 6.3V 100u R2209 3.3k C2171 50V 1000p C3025 10V 1u R2186 220 R2389 1k ZA2104 TESA169 R3099 220 C3039 50V 0.01u R2137 33k D3052 MAZ81400ML C2131 50V 0.1u C2142 50V 0.01u R3075 220 Q2315 B1ABDF000034 C2170 50V 1000p R2187 220 PA3100 K5H1622A0023 C2175 50V 0.01u Q2106 B1ABDF000034 C3051 50V 0.01u R2224 0 R2237 10k C2132 16V 10u C2197 6.3V 2.2u R2225 0 C3055 10V 1u R2116 J0JCC0000241 C2157 16V 1u C3027 10V 1u Q2102 2SA207700L C2133 50V 47p C3023 10V 1u R2165 1k C2203 50V 10p R3092 220 C3028 10V 1u C3036 50V 0.01u C2140 50V 0.01u C3030 16V 0.1u SUB5V R2182 100 R2213 10k L2110 J0JCC0000100 D2119 B0BC01100001 R3114 0 R2128 100 R2388 1k L2184 J0JCC0000241 R2235 10k ZA2107 TESA169 R2197 470 R2171 220 L2123 J0JCC0000241 L2107 J0JCC0000100 C2372 50V 10u R2238 0 C2159 16V 1u R2167 220 C2161 16V 100u C2213 0 D3051 MAZ81400ML R3101 220 C0ABBA000168 IC2104 1 2 3 4 5 6 7 8 C3050 10V 1u C2146 50V 0.1u C2174 50V 1000p SUB5V_MSP R3045 0 AN15862A-VT IC2105 1 L1 2 R1 3 L2 4 R2 5 VCC 6 L3 7 R3 8 L4 9 R4 10 L5 11 R5 12 L6 13 R6 14 L7 15 R7 16 L8 17 R8 18 L9 19 R9 20 L10 21 R10 22 O1 23 LOUT5 24 ROUT5 25 LOUT4 26 ROUT4 27 LOUT3 28 ROUT3 29 GND 30 LOUT2 31 ROUT2 32 LOUT1 33 ROUT1 34 ADR 35 SCL 36 SDA 37 O2 38 BIAS 39 L11 40 R11 41 L12 42 R12 43 L13 44 R13 R2169 4.7k R3097 220 L2187 J0JCC0000241 R3044 0 L2204 0 ERJ3GEY0R00V C3045 10V 1u C2204 50V 22p R3080 0 C3052 50V 0.01u R2129 100 D3050 MAZ81400ML D3024 B0BC01100001 R2399 1k ZA2105 TESA169 R3074 220 ZA2103 TESA169 L2108 J0JCC0000241 R2155 220 L2115 J0JCC0000241 ZA2102 TESA169 IC3005 AN15867A-VT 1 C3 2 S-3 3 V4 4 Y4 5 PDD2 6 C4 7 VCC1 8 C5 9 PDD1 10 V5 11 Y5 12 GND1 13 V6 14 V7 15 V8 16 V9 17 CY1 18 SPD1 19 PB1 20 PR1 21 IPD1 22 CY2 23 APD1 24 PB2 25 PR2 26 SPD2 27 CY3 28 IPD2 29 PB3 30 PR3 31 APD2 32 CY4 33 PB4 34 PR4 35 SDA 36 SCL 37 VOUT6 38 VOUT4 39 VCC2 40 COUT3/VOUT7 41 VOUT3 42 YOUT3/VOUT5 43 GND2 44 PRout2 45 PBout2/Cout2 46 CYout2/Yout2/Vout2 47 DCOUT 48 PRout1 49 PBout1/Cout1 50 CYout1/Yout1/Vout1 51 VOUT 52 SA1 53 V1 54 Y1 55 S-1 56 C1 57 SA2 58 V2 59 Y2 60 S-2 61 C2 62 SA3 63 V3 64 Y3 SUB9V_VIDEO C3067 50V 0.01u R2153 220 R2396 10k C2143 50V 0.01u L3000 G0C101K00023 R3062 220 C3035 10V 1u C2128 50V 0.1u SUB9V C3054 10V 1u C2162 16V 1u C2168 16V 1u JS2109 0 C2239 50V 0.01u R3076 0 R2236 10k R2164 220 R3174 220 R3072 220 R2215 0 R2160 220 C2148 16V 1u R2390 20k Q2314 B1ABDF000034 C_DVSS L2118 EXCELDR35V 1% R3234 75 PA2055 K5H1622A0023 L2206 J0JCC0000241 C3022 10V 1u L2109 J0JCC0000100 JS2124 0 C2116 50V 0.1u L2183 J0JCC0000241 C3026 50V 0.01u C2153 16V 4.7u C2202 50V 5p L2186 J0JCC0000241 C2178 16V 10u R2173 220 L3009 J0JCC0000100 Q2317 B1ABDF000034 C2185 50V 0.1u R2154 22 R3057 0 R3087 220 R3058 0 R2234 10k R3176 220 C2129 10V 1u C2118 16V 47u C2176 50V 0.01u 1% R2149 63.4k JS2123 0 C2190 16V 1u C3075 16V 220u C3043 10V 1u C2149 16V 1u R2176 220 C3041 50V 0.01u C3047 10V 1u R2196 100k R2397 47k C3021 10V 1u R2183 100 R3175 220 R2166 1k SUB9V_VIDEO L2185 J0JCC0000241 C2160 16V 1u R2391 10k R3063 220 JS3029 R2202 100 IC2103 AN77L08M-E1 IN 3 2 COM OUT 1 R2192 220 MAIN9V C3070 16V 0.1u Q2316 B1ABDF000034 R2398 12k C3024 10V 1u R3089 22 R2113 0 ERJ3GEY0R00V R2124 100 C2126 50V 1000p R2208 470 2.0 x 1.25 R2210 1.2k R2125 100 1% R2148 63.4k C2183 3.3u 50V R2126 4.7k C2181 50V 0.1u MSP_ANALOG POWER/1 AVSW/1 AVSW/2 POWER/2 MSP/DIGITAL SOUND/SIF DVSUP SPEAKER L MAIN HP out MAIN in HEADPHONE R SUB in HEADPHONE L SPEAKER R DIGITAL GND L AHVSS VREFTOP NC R (MSP4450K-QA-D6) VCC MUTE SW GND AGNDC 8V H-BOARD TNPA3760AD (2/3) TH-42PV65C H-Board (2 of 3) Schematic Diagram TH-42PV65C H-Board (2 of 3) Schematic Diagram 78 14.17.H 电路板 （3/3）线路图 21 27 25 26 24 19 22 23 20 11 12 13 14 15 16 ! + + KEY1 SUB_PB 5.00V 0.0V SD_REC_V 9.0V G_LED STBY_LED AV4_VGND MAIN_PB AV4_CGND 9.0V SD_IRQ SD_RST SD_AUDIO_GND MAIN_Y MAIN_SW2 SUB_PR SUB_Y PC_GND_G MAIN_SW1 PC_GND_B MAIN_PR PC_GND_R 9.0V AFC2 VOUT5 AI_SENSOR AGC2 AGC1 AGC1 AGC2 MSP SUB_SW1 SUB_SW2 KEY_EDGE AFC1 MAIN_Y_OUT MAIN_PB_OUT SUB_Y_OUT SUB_PB_OUT SUB_PR_OUT SOS SOS SOS RST MSP_RESET SP_MUTE AUDIO_MUTE SDA0B SCL0B AD_BICK AD_DAT AD_LRCK PC_V PC_H PC_B PC_G PC_R SUB_Y SUB_PB SUB_PR MAIN_PB MAIN_PR MAIN_CVBS MAIN_Y SR_GND SR SL_GND SL AMUTE SUB3.3V HDMI_SR HDMI_SL SD_TXD SD_RXD HP_LOUT HP_ROUT AV4_YGND MAIN_SW1 MAIN_SW2 SUB_SW1 SUB_SW2 SUB_RF_GND SUB_RF_CVBS MAIN_RF_GND MAIN_RF_CVBS ACTIVE_STB_LED AV4_L AV4_Y AV4_R AV4_C AV4_V SD_IRQ SD_RST SD_TXD SD_RXD 5.00V 30V 30.00V 30.00V SCL0B SDA0B RM_IN MAIN_PR_OUT MAIN_CVBS AFC2 AFC1 ACTIVE_STB_LED RM_IN 5.00V KEY1 KEY_EDGE AV4_S G_LED STBY_LED AI_SENSOR CL071 R3206 100 JS3252 0 R3250 0 JS3352 J0JCC0000241 C3230 50V 0.1u CL053 SUB5V JS3363 JS3256 0 C5604 50V 10u CL221 CL068 ZA3401 K4CZ01000027 JS3202 J0JCC0000241 CL078 CL077 R3214 0 SUB9V CL056 CL055 ZA3405 K4CZ01000027 H1 K1KY80A00011 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60 61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80 JS3215 0 SUB5V C3253 16V 0.1u CL034 H5 K1KA15AA0288 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 R3263 0 1% R3120 91 CL129 JS3358 J0JCC0000241 Q3014 VIDEO/1 2SA207700L SUB3.3V C0DBAJB00004 IC5603 1 VOUT 2 VDD 3 NC 5 EXT 4 VSS ZA3403 K4CZ01000027 CL073 R3266 0 C3063 50V 0.1u 1% R3354 150k CL054 JS3355 J0JCC0000241 CL047 C3227 10V 10u JS3304 SUB5V D3023 MA2J11100L CL044 Q3011 2SA207700L 1% R3123 130 C3241 50V 0.1u R3259 220 JS3035 0 PA3104 0 C3059 16V 1u SUB9V R3254 0 R3215 J0JCC0000241 JS3354 J0JCC0000241 1% R3135 91 D3021 MA2J11100L 1% R5612 16k Q3210 2SA207700L BT30V C3062 50V 0.1u JS3205 J0JCC0000241 C3064 50V 0.1u JS3303 C3216 10V 10u R3213 0 C5686 50V 0.01u CL065 R3290 4.7k R3253 220 SUB5V Q3204 B1ABDF000034 JS3356 J0JCC0000241 MAIN9V C3248 1u 16V C3257 16V 0.1u R3102 6.8k JS3002 JS3368 SUB5V_MSP R3219 100 R3227 0 1% R5611 82k CL066 H15 K1KA04AA0150 1 2 3 4 R3049 220 H40 K1KA20AA0009 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 JS3244 J0JCC0000241 C3208 16V 0.47u 1% R3140 130 C3233 50V 0.1u CL046 STB+B BT30V CL074 JS3033 0 JS3230 0 CL025 R3284 0 R3122 100 CL182 C5685 50V 10u CL057 CL022 JS3357 J0JCC0000241 SUB8V R3264 0 CL023 CL058 MAIN3.3V CL049 JS3246 0 1% R3121 130 R3240 10k R3261 0 L5610 G1C470MA0077 CL033 C3226 10V 10u JS3206 0 R3229 0 R3291 4.7k R3256 0 CL043 C3214 10V 10u R3241 10k R3255 560 R3048 22k CL067 R3118 100 R3160 1k 1% R3138 100 CL036 Q3207 B1ABDF000034 CL183 C3249 16V 0.47u CL045 CL080 R3242 10k C3254 16V 0.1u Q3015 2SA207700L CL051 Q3008 2SA207700L ZA3402 K4CZ01000027 R3278 0 D3044 MA2J11100L R3267 0 R3281 0 R3286 J0JCC0000241 CL075 CL021 JS3255 0 R3224 0 JS3237 0 C3228 10V 10u CL060 JS3239 0 CL219 D3022 MA2J11100L CL024 R3228 0 CL070 C3252 1u 16V R3127 1k L5608 G1C100MA0072 CL072 D5618 B0BC03900015 JS3359 J0JCC0000241 C3262 50V 4700p STB+5V JS3245 J0JCC0000241 R3141 1k R3161 1k CL069 STB+5V L5605 G1C1R0MA0072 L3219 J0JGC0000021 JS3302 Q3205 B1ABDF000034 CL061 Q5614 B1CFNG000001 R3239 10k C3207 1u 16V SUB5V C3256 1u 16V JS3362 CL059 R3283 0 R3115 100 1% R3119 91 STB+B R3126 100 R3262 0 Q3206 B1ABDF000034 JS3034 0 R3238 0 C3251 16V 0.1u R3050 2.4k R3051 6.8k H6 K1KA15AA0288 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 SUB9V_VIDEO JS3265 0 CL035 H51 K1KA30AA0009 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 R3279 0 L3212 J0JCC0000100 H2 K1KA15A00148 BM15B-GHS-TBT(LF)(SN) 1.25 1 2 3 4 5 6 7 8 9 10 11 12 13 14 16 17 15 C3268 50V 0.01u CL124 1% R3353 270k D5610 MA3X78900L JS3266 0 CL050 R3251 0 CL064 SUB3.3V R3139 1k Q3017 2SA207700L CL048 L3216 J0JGC0000021 CL062 CL220 R3125 1k SL_GND SL_GND GND SL GND SOS STB5V GND SL STB3.3V 2Vpp to ADV SP_MUTE GND SUB_SW2 2Vpp to ADV GND MAIN_SW2 GND AUDIO_MUTE SCL0B 2Vpp to ADV GND GND 2Vpp to M2 GND GND 2Vpp to GC3FS GND MAIN_SW1 2Vpp to GC3FS GND SUB_SW1 GND GND SUB5V GND AD_LRCK GND NC GND SDA0B GND GND GND A_MUTE AD_DAT GND TO G51 GND GND MAIN_L MSP_RESET GND RST BS_SL GND BS_SR MAIN3.3V GND GND NC GND MAIN_R GND PC_V GND SUB_PR SUB3.3V GND SUB_Y GND MAIN9V PC_H GND HDMI_SL GND PC_B BT30V PC_G GND SUB_PB SUB3.3V GND SUB9V AD_BICK PC_R NC DVB_CVBS GND MAIN_CVBS SUB5V MAIN_PB 1Vpp to SD_REC SR 2Vpp to GC3FS SR MAIN_Y GND BT30V MAIN_PR STB5V SR_GND SD_RX SD_TX SD_IRQ SD_RST GND STBY_LED G_LED RM_IN KEY1 AI_SENSOR GND KEY_EDGE AFC1 AFC2 Active_STB_LED GND EURO\ASIA SR_GND HDMI_SR TV_V2 AFT2 SDA0B TV_V2_GND GND GND GND GND SCL0B TV_V1 TV_V1_GND GND AGC2 GND SUB_SW1 GND GND MAIN_SW2 AGC1 GND GND GND SUB_SW2 SIF SUB5V AFT1 SUB30V AM SUB5V MAIN_SW1 NC HP_MUTE HP_R HP_L V_DET KEY_EDGE STB5V HP_GND MAIN_L MAIN_R STBY_LED HP_GND GND AV4_R G_LED AV4_V AV4_L AV4_S SUB5V AV4_Y GND AI_SENSOR ACTIVE_STB_LED GND GND GND GND RM_IN GND SUB_MONO GND AV4_C KEY1 HP_DET AE AD AC AF AB AJ AH AG VCC H-BOARD TNPA3760AD (3/3) TH-42PV65C H-Board (3 of 3) Schematic Diagram TH-42PV65C H-Board (3 of 3) Schematic Diagram 79 14.18.TA 电路板线路图 3 9 7 A 8 6 E C D B 1 F 4 5 2 + + 0V 0V 0V 0V 0V MAIN_SW1 MAIN_SW2 0V 0V 30.00V 0V 5V GUARD_A SIF 0V 30.00V SCL0B GUARD_CLK SCL0B SDA0B GUARD_CLK 30.00V 5.00V 0V SCL0B SDA0B MAIN_SW1 MAIN_SW2 GUARD_CLK GUARD_CLK SUB5V 5.00V GUARD AFT1 SIF TV_V1 0V TV_V1_GND TV_V1 TV_V1_GND SDA0B 5.00V AFT1 5.00V L001 J0JGC0000021 CL018 C030 50V 33p Q002 2SA207700L R022 220 C029 50V 33p R014 0 CL009 CL016 R009 220 R017 22 C002 10u 50V CL011 1% R029 270k JS012 ERJ3GEY0R00V 0 C008 16V 0.1u CL010 1% R028 150k CL007 CL013 L031 J0JGC0000021 TU001 ENG39A26GF NC 1 NC 2 BM 3 NC 4 SW1 5 SW2 6 BT 7 RF_AGC 8 NC 9 SCL 10 SDA 11 AFT 12 AUDIO_OUT 13 SIF_OUT 14 BTL 15 IF_OUT 16 VIDEO_OUT 17 R020 0 TA5 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 L007 J0JCC0000241 TA6 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 R011 270 C041 16V 0.1u CL014 L011 J0JCC0000241 C011 50V 33p R008 0 CL017 L032 J0JGC0000021 CL008 R019 0 R005 560 L013 J0JCC0000241 C042 16V 0.1u L010 J0JCC0000241 CL015 R001 1k C010 50V 33p L021 0 CL002 C009 50V 100p R023 0 R018 22 C016 16V 0.1u CL012 C003 50V 0.1u R021 1k C006 6.3V 1000u TV_V1 AFT1 GND TV_V1_GND SCL0B BT30V GND GND GND GND AFT2 GND TV_V2 SDA0B MAIN_SW1 SUB5V GND GND GND RFAGC2 SUB_SW1 SUB_SW2 GND SUB5V MAIN_SW2 RFAGC1 GND NC SIF TV_V2_GND ! TH-42PV65C TA-Board Schematic Diagram TH-42PV65C TA-Board Schematic Diagram TA-BOARD TNPA3768AE 80 14.19.G，GK，HC 和 K 电路板方框图 R V L Y C C Y G CY-G G R2 R1 T NC1 SW1 NC2 SW2 R-SW R R-G L L-G V-SW V V-G NC3 SW3 IC2511 SW3754 +/ SW3757 SW3755 F SW3753 -/ STR TV/AV SW3756 STB3.3V AI SENSOR SUB5V K1 5 RM2501 Q2511 8 2 11 6 ON/OFF Q2513 ON/OFF REMOTE RECEIVER/LED 9 VCC Q2510 REMOCON RECEIVER K VOUT RM_IN D2520 8 G1 9 2 6 5 G3 2 KEY1 GK3 FRONT TERMINAL G KEY SWITCH GK 2 1 1 KEY2 POWER LED R_LED_ON /STBY_LED /KEY_EDGE TO H51 AV4_S G51 KEY_EDGE V_DET RM_IN KEY1 AI_SENSOR STB3.3V SUB5V AV4_C AV4_Y AV4_V AV4_L AV4_R 14 4 22 8 25 29 20 18 24 6 27 7 10 9 R_LED_ON /STBY_LED S-VIDEO COMPOSITE HEADPHONE JK3701C AV4 IN MAIN_R 17 19 MAIN_L AI SENSOR AI SENSOR TH-42PV65C G, GK and K-Board Block Diagram TH-42PV65C G, GK and K-Board Block Diagram 21 10 MAIN ROUT DEVICE HC01 HC22 FACTORY IIC1 6 7 SD_RX 9 12 5 1 OUTPUT OF DVB 2 3 SUB5V IIC2 SDA0A SRQ1 17 GND SDA0B SD_RX SCL1 15 SD_TX SCL0B SCL0B 14 HC21 6 1 2 2 16 12 4 13 FACTORY STB5V 6 14 GND 9 SRQ SCL0A HC12 3 5 10 SDA0A 7 TO DG15 11 1 18 17 HC15 40 38 15 D_STB3R3V JIG CONNECTION D_IIC_CONT D_SDA2 35 IIC0 USE D_SCL2 36 34 33 D_TXD EEPROM ROUT D_RXD 29 19 26 D_PSTB 28 SUB ROUT DEVICE D_PBUSY 31 D_PDB1 8 D_IIC_INT + PANEL MICOM D_PSLCT D_PDB0 32 27 SCL1 REMOCON SDA1 G_LED SDA2 23 SCL2 22 20 5 4 25 IIC0B SDA0B D15V INPUT TO DVB SCL0A 1 STB5V SCL0B SRQ FACTORY SRQ 24 USE 19 STB5V 9 R_LED FOR 5 SDA1 SCL0A 11 11 18 4 SCL2 SDA2 USE 8 SDA0A FOR 6 HIGH SPEED DEVICE ROUTE SD_TX FOR 8 HC 2 FACTORY USE FOR 8 SDA0B SCL2 9 7 SDA2 7 SDA0A 6 SCL0A 81 14.20.G 电路板线路图 R V L Y C C3703 560p 50V R3710 0 L3708 J0JCC0000100 R3740 0 R3716 180k R3733 0 JK3701C K4AK22B00002 C Y G CY-G G R2 R1 T NC1 SW1 NC2 SW2 R-SW R R-G L L-G V-SW V V-G NC3 SW3 D3702 MAZ81400ML R3746 0 JS3716 0 L3707 J0JCC0000100 JS3711 0 JS3705 0 R3711 0 R3714 0 JS3708 0 L3701 J0JCC0000364 R3721 10k JS3714 0 R3717 180k R3738 0 C3712 50V 0.033u C3711 50V 0.033u R3741 0 C3701 560p 50V G3 1 2 3 R3737 0 ZA3701 K4CD01000013 R3709 0 R3748 0 JS3707 0 G1 1 2 3 4 5 6 7 8 9 10 11 12 L3700 J0JCC0000364 R3704 0 JS3713 0 G51 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 R3732 0 R3736 0 R3739 0 JS3712 0 JS3704 0 SUB5V G_LED_ON GND GND AI_SENSOR G_LED_ON AI_SENSOR MODEM_LED/KEY3/ Active_STBY_LED STB3.3V MODEM_LED/KEY3/Active_STB_LED STB3.3V SUB5V RM_IN RM_IN GND GND R_LED_ON/STBY_LED GND PSM_LEDR GND KEY2/KEY_EDGE KEY1 GND KEY1 PSM_LEDR/KEY2/KEYEDGE GND GND HP_DET R_LED_ON/STNBY_LED HP_GND GND MAIN_L MAIN_R SUB_MONO HP_GND AV4_C AV4_R AV4_L AV4_S V_DET AV4_Y AV4_V GND GND GND SUFFIX AF B 1 2 6 7 8 A C E 5 3 D 4 (GK3) GK-BOARD TO TO K-BOARD (K1) (H51) H-BOARD TO S-VIDEO COMPOSITE HEADPHONE G-BOARD TNPA3764AF ! AV4 IN < TH-42PV65C G-Board Schematic Diagram TH-42PV65C G-Board Schematic Diagram 82 14.21.GK 和 K 电路板线路图 STB3.3V D2510 MA8056MTX R2521 47 R2516 22k D2511 MA8056MTX K1 1 2 3 4 5 6 7 8 9 10 11 12 R2520 220k RM2501 PNA4701M05TV VOUT GND VCC C2521 0.01u 50V R2512 47 C2510 16V 1u C2511 16V 1u R2557 5.6k R2517 47 IC2511 B3L000000020 Q2511 B1ABCF000138 R2542 47k Q2510 B1ABCF000138 D2524 MA8056MTX R2524 22k D2512 MAZ80430LL C2512 6.3V 10u C2515 50V 0.01u SW3754 EVQ11G05R SW3756 EVQ11G05R R3751 6.65k R3768 0 R3758 3.16k R3762 0 R3765 2.32k R3764 0 SW3755 EVQ11G05R R3753 1.62k R3759 0 R3763 0 C3751 1000p 50V SW3753 EVQ11G05R R3757 1.74k R3761 0 SW3757 EVQ11G05R R3760 0 GK3 1 2 3 R3754 2.32k R3755 0 C3750 1000p 50V R3767 3.16k R3750 14.3k AI SENSOR REMOTE RECEIVER STBY3.3V GND AI_SENSOR GND G_LED_ON REMOCON Modem_LED/KEY3 PSM_LEDR Active_STB_LED GND SUB5V R_LED_ON/STBY_LED GND GK-BOARD TNPA3848AD 5 6 D E C A 7 1 B 3 4 2 8 (G3) TO G-BOARD ! TO (G1) G-BOARD TV/AV -/ F +/ STR GND KEY KEY2/KEYEDGE K-BOARD TNPA3762AE TH-42PV65C GK and K-Board Schematic Diagram TH-42PV65C GK and K-Board Schematic Diagram R G STB_LED R2558 0 1% R2525 576 R2530 22k Q2513 B1ABCF000138 R2556 5.6k D2520 LNJ107W5PRW 1% R2531 270 83 14.22.HC 电路板线路图 3 9 7 A 8 6 E C D B 1 F 4 5 2 ! 18 16 14 12 10 8 6 4 2 20 21 19 17 15 13 11 9 7 5 3 1 HC21 B8B-PH-K-S(LF)(SN) K1KA08AA0193 1 2 3 4 5 6 7 8 JS3405 0 JS3403 HC22 B11B-PH-K-S(LF)(SN) K1KA11AA0194 1 2 3 4 5 6 7 8 9 10 11 HC12 K1KA09AA0190 B9B-EH-F1(LF)(SN) 1 2 3 4 5 6 7 8 9 HC15 K1KY40B00003 1871335-1 0.5 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 JS3404 0 JS3402 HC01 K1KA21A00011 BM21B-SHLVS-G-TBT(LF)(SN) 1 2 SD_TX G_LED R_LED RIMOCON SD_RX SDA0B SCL2 SDA2 SRQ1 IIC0B GND IIC2 IIC1 IIC0 EEPROM STB5V SCL0A SDA0A SCL0B IIC_CLK2 IIC_DATA2 TXD RXD IIC_CONT IIC/INT P15V PSTB STBY3.3V PBUSY PDB0 PSLCT PDB1 STB5V GND STB5V SRQ1 SCL1 SDA1 SCL2 SDA2 SDA0B SRQ1 GND STB5V SCL0A SDA0A SCL0B NC SDA0A SCL0A HC-BOARD TNPA3852 TH-42PV65C HC-Board Schematic Diagram TH-42PV65C HC-Board Schematic Diagram 84 14.23.DG 电路板 （1/3）方框图 HDMI_DAC_PD RX_MCLK HDMI_RST MUTE_OUT 3.3V_SDA RX_SCK RX_SD0 HDMI_INT RX_WS 3.3V_SCL HSIB REFCH_HDMI VSIB CLKINB2 AP_DE HPD2 HDMI_CEC HDMI_5V_DET HPD1 HDMI_5V_DET1 HDMI_WP 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 Divider CLK+ 5 INTERFACE S1 D1+ H:MUTE AUDIO DAC TMDS DECODER D2- 1 141 WS 119 SDA AUDIO D2G ROX1+ HPDT CEC IC4025 SD0 VIDEO (TO GC5 PORT-B) Interpolator YBIN0-YBIN9 HDMI 1 IN S2 2 BICK Modulator 5V MCLK 7 TMDS DECODER Interpolator +5V 1 INTERFACE ROX1- Q4069 INT D2 D2+ EEPROM SCL HDCP CIPHER DECRYPTOR 4 ROX2- D1- AND AOUTL INTERFACE 7 D0+ RECEIVER 123 R RECEIVE 8X DDCG P AOUTR 3 D1 R1X0+ DG9 142 L DDC DATA 102 Clock R1X0- Data R1XC- R1X1- DSCL0 HDCP D0G 2 110 Modulator MUTE OUT N.C. 3.3V 104 IC4023 Q4070 132 INTERFACE R1X2- R1X1+ TMDS DATA AND CPU D0- 6 SCK 8X PDN R1X2+ AUDIO RESET ROX2+ 6 MAIN9V SCL ROXC- DSDA0 ROXC+ 3 MCLK LRCK AUDIO AMP 136 CLKG D1G R1XC+ UBIN0-UBIN9 IC4028 TMDS DATA WC CIPHER DECRYPTOR 133 5 ROX0+ SMUTE ROX0- SDTI CLK- 52 51 48 47 39 43 40 44 66 70 62 63 67 71 59 58 32 31 77 88 86 84 85 1 6 2 3 4 5 10 11 VSYNC HSYNC ODCK 121 97 3 1 2 MAIN 1.8V XTALIN MAIN 3.3V DE HDMI I/F RECEIVER IC4026 MAIN 5V D0- CEC DDC DATA +5V N.C. HPDT CLKG D2+ D0+ D1+ CLK+ CLK- D2- DDCG D1- D1G D2G D0G SCL IC4022 SCL 5 SDA EEPROM 6 7 WC 3.3V Q4071 D1 5V S2 S1 D2 DDC_SDA0 DDC_SCL0 DDC_SDA1 DDC_SCL1 29 30 33 DSDA1 DSCL1 R1PWR5V 3.3V_SDA 3.3V_SCL Q4083 Q4068 Q4065 CABLE OUT;LOW/MUTE CABLE IN;Hi/NORM HOTPLUG Low;DETECT HPD5V AUDIO MUTE AND 5V DET Hi;MUTE CSCL CSDA 28 27 SCL1 SDA1 HDMI 2 IN DG8 Q4082 Q4067 Q4066 HOTPLUG MAIN 5V 34 R0PWR5V CABLE OUT;LOW/MUTE CABLE IN;Hi/NORM AUDIO MUTE AND 5V DET Hi;MUTE Low;DETECT HPD5V MAIN 1.8V CONT 5 VIN VOUT 1 MAIN1.8V IC4027 MAIN 3.3V 7 DIGITAL SIGNAL PROCESSOR HDMI INTERFACE DG MICOM Q4084 TH-42PV65C DG-Board (1 of 3) Block Diagram TH-42PV65C DG-Board (1 of 3) Block Diagram 85 14.24.DG 电路板 （2/3）方框图 TH-42PV65C DG-Board (2 of 3) Block Diagram TH-42PV65C DG-Board (2 of 3) Block Diagram MATRIX 8 1 HSIA SYNC 14 DETECT 36 DDR2.5V I/P CONV. 625i/p VIN 12 SCL TRST 11 IC4032 HS IC4019 PORT-A A_DDR_CLK TCK DCLK_IN RESET 3D/2D com (ADV7499) (FS&HDMI) 3D Y/C SDA I/F MAIN1.2V VSIA NR PORT-B 78 4 8 A_DDR_NCLK MIX Sync REFCK_ADV 10bit A/D(ADV7499) SCL2 IC4038 RESIZE 1080i 720p 35 IC4037 SEPA 7 MAIN1.8V XTAL CHROMA SW CLK 99 MAIN 1.2V COLOUR INPUT DDR 2.5V SDA2 DIGITAL Macrovision VOUT 13 TMS MAIN3.3V 38 DEM. ->YUV VS CLKIA CK TDI VOUT CLK0A SELF,ID,ED2 YBIN0-9,UBIN0-9 NOISE LEVEL NRST 128M DDR SDRAM IC4035 CK LLC1 1 Detection RGB 525i/p JTAG VPK VIN CLKINB2 VSIB AP_DE HSIB REFCK_HDMI 5 CONT 5 CONT YIN0-YIN9 UVIN0-UVIN9 RIN0-RIN3 10 13 14 91 94 22 29 42 41 30 33 GC5 PROCESSOR SDA 1 VOUT MAIN_PR DG2 A/D 10bit AI_SENSOR 4 9 VDD Q1115,Q1113 MAIN 3.3V AIN1 5 1 82 PC_VS SCL2 A_MON_MUTE A/D 10bit 86 SR STBY3.3V 5 1 VDOUT STBY3.3V VOUT 10 IC4016 KEY1 16 SOS 12 VIN IC4013 27 1 110MHz SUB3.3V 49 MAIN3.3V MAIN_PB/C SDA2 74 SCL0B IC4029 1.8V AUDIO MUTE 29 AFC1 80 AVR 1.8V SDA0B 3 STB 1.5V 4 Q1130 STB1.5V ON/ KEY_EDGE VS_IN 54 TO SL VIN VDD 2 1 AD 3.3V Q4050,Q4058 AIN4 110MHz AVR 1.8V 5 8 5 43 51 73 MAIN_Y/CVBS 76 PC_R 5 STB 3.3V STBY3.3V AD 3.3V VOUT 1 8 H1 SCLK VOUT 78 IC1110 PLL3.3V RM_IN H2 PLL 3.3V 15 AIN6 VIN 45 VIN CONT SP MUTE 65 MAIN 5V 6 56 IC4030 MAIN5V 1.8V TO 63 72 85 RST STBY5V OFF HDMI_R SUB3.3V MAIN3.3V 5 Q4056 81 VOUT 7 STBY_LED 4 67 4 3 110MHz PC_B AIN3 IC1111 47 7 MAIN1.8V 5 13 PC_HS VOUT 1 SDA0B AIN5 IC4018 VOUT HS_IN VIN IC4027 AIN2 PC_G MAIN3.3V DLL 2.5V SCL0B 58 1 A/D 10bit 6 5 RESET VOUT 1 8 DLL 2.5V HDMI_L DG1 VIN FAN_SOS SR MAIN5V SUB5V 29 SUB9V 32 SUB5V 8 SOS MAIN3.3V MAIN9V 22 33 23 SOUND_SOS DG20 28 38 SUB5V MAIN3.3V 18 7 MAIN1.8V 17 MAIN5V 25 35 24 SUB_ON PA20 MAIN3.3V 40 2 6 MAIN3.3V 21 MAIN5V MAIN9V TO 9 FAN_MAX MAIN1.8V 4 SUB 9V SUB 9V MAIN1.8V 39 SL SUB 9V TUNER TV_MAIN_ON RGB_CVBS 61 59 RGB_FB Q1140,Q1141 D1107 RST SUB5V Q1116,Q1114 Q1108,Q1111 STBY5V MAIN 1.8V CONT 5 77 SL SR 74 Q4053,Q4055 57 AIN9 51 FB EURO TEXT Q1134 Q4057 D1106 R1321 R1307 DIGITAL SIGNAL PROCESSOR HDMI INTERFACE DG MICOM Q1131 Q1135 _MSP.RESET SW OFF DET RM_IN MAIN_PR AFC1 MCU_RST KEY1 AUDIO_MUTE STBY_LED MAIN_PB/C SL FAN_MAX SOUND_SOS TV_MAIN_ON SR FAN_SOS SOS SOS TV_SUB_ON PC_R PC_G PC_B PC_HS PC_VS RGB_FB RGB/CVBS MAIN_Y/CVBS A_MON_MUTE_MSP_RESET SL SR SOS SP_MUTE KEY_EDGE AI_SENSOR RST MAIN_Y/CVBS MAIN_PB/C MAIN_PR PC_G RGB_FB PC_B PC_R PC_HS PC_VS CVBS0 AI_SENSOR RGB/CVBS CVBS1 B_DDR_CLK B_DDR_NCLK CLKINB2 HSIB VSIB AP_DE REFCH_HDMI GC_RST 86 14.25.DG 电路板 （3/3）方框图 TDO HDMI_INT SOS GENX_X_V GENX_X_H GENX_R0-R4 HDMI_RST KEY1 PANEL_SOS GENX_B0-B4 PANEL_STATUS TDI(FS) FAN_SOS ECO_ON PANEL_STB_ON FAN_MAX DISPEN TV_MAIN_ON GENX_X_CLK SOUND_SOS HDMI_5V_DET1 GENX_YS TMS PANEL_STB_ON ECO_ON DISPEN GENX_G0-G5 STBY_LED MCU_RST GENX_YM PANEL_STATUS PANEL_SOS TV_SUB_ON ALL_OFF WP RST GC_RST WP RM_IN AFC1 KEY_EDGE AI_SENSOR HDMI_CEC CVBS0 HDMI_DAC_PD CVBS1 GENX_HO GENX_CLKO HDMI_WP ALL_OFF HPD2 HDMI_5V_DET2 AUDIO_MUTE SP_MUTE HPD1 D_PSLCT(PSCLT) TX_TE- REMOCON 9 117 D_RXD 4 109 IC4037 SDA0B OSDXI 20 2 PORT_E SDATA STBY_LED GAMMA TX_TD+ D_IIC_INT 17 4 D_IIC_INT(IIC_INT) SRQ XRST DTV_EEP_SCL ECO_ON R_LED IRQ4A STBY5V_DET 13 SCL0B 13 TUNER_SUB_ON YSOUT 11 SCL2 TRCD0 SCL2 103 MAIN3.3V_DET TX_TB- R04 PORT_D DISPEN(DRVMUTE) SCL1 DG3 18 37 D_RXD D_PDB0 1 107 13 FLASH FACTORY DG5 TDO 206 3 TX_TE+ 186 DTV_EEP_SDA 165 20 TRCD3 174 GENX_YS 1 9 GENX_HIN 105 Q1101,1139 1 33 32 178 TO 209 TO 17 100 Q1102 SDA0A 208 WP 7 TX_TA+ 29 TV_MAIN_ON CECINA 16M KEY_EDGE FOR IIC/SERIAL 110 VMUTE 102 FOR EXTRG0 TX_TD- 5 13 14 33 MAIN MICOM 7 ALARM Q4063 133 D_15V(P15V) (OSD INPUT) 22 D_TXD 30 OSD MIX VSOE TX_TCLK+ X1101 Q4061 D_PDB1(PDB1) RST 5 STBY3.3V 16 1 POWER_SOS 171 Q4064 TO D5 132 R00 23 STBY3.3V 187 FOR ROM(D-BOARD) TRCD3 G_LED(LED_G) DG7 180 6 D_SCL2(IIC_CLK2) 40 1 122 SDA1 22 Q4062 LVDS_PD 5 STBY3.3V D_15V PANEL STATUS 14 (DEBUGER) TX_TCLK- 138 TDI 179 4 D_PBUSY(PBUSY) SUB9V Q1142,Q1143 TRCCLK IC1101 PANEL_STBY_ON CONVERTER SCL0A READY(STATUS) 116 SDA2 TRCD2 215 HC15 TRCD2 FOR 95 USE 184 6 ALL_OFF RTCXO SCL0A 3 12 136 TRCD1 38 160 Q1100 112 FAN_SOS SCL1 5 9 GENX_CLKIN TRCD1 6 SDA0B 29 216 USE 15 CONT MAIN3.3V TMS D_PSTB 175 8 3 B00 X1100 CLKOE PANEL SCL1 D/A OSD PIXEL CONV. DG15 FACTORY 111 SCL2 D_PSLCT 159 135 11 G_LED PANEL_STB_ON 61 14 SCL1 3 SRQ 8 REMOTE IN D3 D_IIC_CONT 15 TV_SUB_ON STBY5V SDA0A GENX_VIN AFC1 26 10 Q1103 4 19 R_LED(LED_R) 211 SXCO D_PDB1 GC_RST SUB5V_DET 97 21 123 IIC_CLK1 2 D_SDA2(IIC_DATA2) 169 14 TRCST 15 212 RTCXI 7 210 D_IIC_CONT(IIC_CONT) 13 SDA2 HDMI_RST 3 21 SCL2 TRCD0 10 168 KEYSCAN1 35 B04 17 STBY5V D_STB3R3V OSCXI TX_TB+ 10 D_PBUSY ECO_ON 27 D_STB3R3V(STBY3.3V) SDATA HSOE 17 RESET NRST SOUND SOS DTV_EEP_SDA 172 6 176 23 PANEL SDA1 16 SUB9V_DET TCK 185 19 DG35 VSYNC 8 TX_TC+ 5 D_SDA2 TX_TA- 27 D_SCL2 197 SDA2 TRCCLK 12 205 19 SCL0CK SCL0A YMOUT0 44 101 G00 173 DTV_EEP_SDA 24 PANEL_SOS TRCST D_PSTB(PSTB) 34 SDA1 SDA0A (RGB OUT) IC1103 FAN_CONT REMOCON HSYNC HDMI_INT AI 128 2 2 11 TX_TC- SCL0CK D_TXD 5 TRST 16 30 SUB5V GC5 PROCESSOR SDA2 STBY5V STBY3.3V EXTRG0 110MHz 3 207 HDMI 5V DET1 D_PDB0 SCL0A SDA1 7 D/A 10bit IIC_DATA1 SDA0A ROM D/A 8bit SCL0B OSD G05 64M IC1100 SDRAM 41 ALL_OFF SDA 5 7 6 SCL0A IC1102 SCL EEPROM SDA0A WP Q1137 SDA1 SCL1 AI_SENSOR 162 46 CVBS0 HDMI_WP 199 142 HDMI_DAC_PD 183 151 CVBS1 GENX_CLKO GENX_HO GENX_R0-R4 GENX_B0-B4 GENX_G0-G5 GENX_YM 4 5 61 59 33 38 (SERIAL) LVDS TRANSMITTER(10bit) 23 29 GOE0~GOE9 55 TB- CLKIN 18 22 LVDS 57 BOE0~BOE9 TC4 TA+ PARALLEL TC- TCLK- 25 TA- 24 20 31 30 TE- TD- TD+ IC4036 DATA 13 /PDWN 12 TE+ 19 TC+ TC5 28 TCLK+ TTL 21 TB+ 8 63 40 62 42 6 11 64 9 1 ROE0~ROE9 44 46 48 50 52 54 10Bit LVDS VCLKOUTA HOUTA 88 87 19 STBY5V STBY5V 195 HDMI_5V_DET2 HPD2 198 MSP RESET AUDIO MUTE 52 45 42 SPMUTE HPD1 196 D1119 DIGITAL SIGNAL PROCESSOR HDMI INTERFACE DG MICOM SD_RX SD_TX 35 36 60 59 AGC1_RX AGC1_TX MSP RESET TH-42PV65C DG-Board (3 of 3) Block Diagram TH-42PV65C DG-Board (3 of 3) Block Diagram 87 14.26.DG 电路板 （1/8）线路图 + AO_A6 AQ_D4 AO_A14 AQ_D13 AR_CLK AQ_D3 AR_RAS EXTRG0 AQ_D10 AQ_D5 PANEL_STATUS AO_A8 AQ_D2 AO_A3 AO_A11 SDA0A AO_A6 ECO_ON AQ_D7 AQ_D9 AO_A7 TRCCLK AQ_D14 AO_A11 AQ_D4 SDATA AO_A12 ALL_OFF AQ_D6 SCLOCK RST AQ_D6 MEMA10 AO_A2 AR_CS TRCST AQ_D10 AO_A9 AO_A19 TRCD3 AQ_D13 AO_A18 AR_CKE AQ_D1 AR_BA0 TRCD2 AR_CAS AP_CE AO_A9 AQ_D15 AQ_D12 TRCD1 TV_SUB_ON AO_A8 AO_A10 AR_LDQM TRCD0 AP_OE AQ_D0 AQ_D11 AQ_D5 AO_A15 AO_A5 AQ_D9 AQ_D11 AQ_D12 AO_A12 AQ_D14 AO_A3 PANEL_SOS AO_A10 AP_WE AO_A17 AO_A4 AQ_D3 AQ_D8 AR_UDQM AQ_D2 AO_A4 AO_A1 AR_WR AO_A13 AQ_D1 AO_A5 AO_A2 AO_A16 AO_A7 DISPEN PANEL_STBY_ON PANEL_SCL1 PANEL_SDA1 D_STB3R3V D_IIC_CONT D_SCL2 D_SDA2 D_TXD D_RXD D_IIC_INT D_15V D_PSTB D_PBUSY D_PDB0 D_PSLCT D_PDB1 AO_A0 RIMOCON R_LED G_LED AQ_D0 AQ_D7 AQ_D8 AQ_D15 STBY3.3V SCL0A AO_A0 STBY3.3V R1122 22 L1101 J0JHC0000078 TP1108 R1412 100k R1454 0 C1110 10V 0.1u C1116 10V 0.1u R1125 3.3k C1109 10V 0.1u R1458 100 C1106 10V 1u R1414 0 C1114 10V 0.1u R1112 100 Q1137 B1ABDF000034 R1113 3.3k R1413 100k C1223 6.3V 10u R1106 1k TP1101 IC1102 1 A0 2 A1 3 A2 4 GND 5 SDA 6 SCL 7 WP 8 VCC DG7 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 STBY3.3V R1111 100 STBY3.3V C3ABPG000145 IC1100 1 VDD 2 DQ0 3 VDDQ 4 DQ1 5 DQ2 6 VSSQ 7 DQ3 8 DQ4 9 VDDQ 10 DQ5 11 DQ6 12 VSSQ 13 DQ7 14 VDD 15 LDQM 16 /WE 17 /CAS 18 /RAS 19 /CS 20 BA0 21 BA1 22 A10 23 A0 24 A1 25 A2 26 A3 27 VDD 28 VSS 29 A4 30 A5 31 A6 32 A7 33 A8 34 A9 35 A11 36 NC 37 CKE 38 CLK 39 UDQM 40 NC 41 VSS 42 DQ8 43 VDDQ 44 DQ9 45 DQ10 46 VSSQ 47 DQ11 48 DQ12 49 VDDQ 50 DQ13 51 DQ14 52 VSSQ 53 DQ15 54 VSS C1102 10V 0.1u R1108 100 R1114 0 TP1109 R1102 1k R1105 1k R1123 47k C1227 50V 100p R1118 EXB2HV680JV R1408 100k R1109 100 C1111 10V 0.1u TP1105 C1100 10V 0.1u DG3 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 R1110 100 TP1104 C1112 25V 270p R1101 100 TP1103 R1124 3.3k C1105 25V 270p C1107 4V 100u R1459 100 R1119 EXB2HV680JV IC1101 1 A15 2 A14 3 A13 4 A12 5 A11 6 A10 7 A9 8 A8 9 A19 10 NC 11 WE# 12 RESET# 13 NC 14 NC 15 RY/BY# 16 A18 17 A17 18 A7 19 A6 20 A5 21 A4 22 A3 23 A2 24 A1 25 A0 26 CE# 27 VSS 28 OE# 29 DQ0 30 DQ8 31 DQ1 32 DQ9 33 DQ2 34 DQ10 35 DQ3 36 DQ11 37 VCC 38 DQ4 39 DQ12 40 DQ5 41 DQ13 42 DQ6 43 DQ14 44 DQ7 45 DQ15/A-1 46 VSS 47 BYTE# 48 A16 R1117 0 TP1102 STBY5V C1226 6.3V 10u C1222 6.3V 10u C1103 25V 270p STBY3.3V R1116 5.6k R1121 22 R1103 1k IIC_CLK1 DISPEN FANMAX ECO_ON GND GND FANSOS PANEL_STB_ON STB5V 16M FLASH GND GND IIC_DATA1 INEXCH READY ALL_OFF GND TUNER_SUB_ON ALARM Panasonic_Mode NC E A 6 7 8 1 C 3 9 B 4 F 5 2 D 64M SDRAM EEPROM G_LED R_LED REMOCON AC_GOOD D_IIC_INT D_RXD D_TXD D_SDA2 D_SCL2 D_IIC_CONT D_STB3R3V D_PDB1 D_PSLCT D_PDB0 D_PBUSY D_PSTB D_15V (D3) D-BOARD TO USE FOR FACTORY (DEBUGER) TRCD2 TRCD0 TRCD1 TRCST TRCCLK TRCD3 SDATA EXTRG0 STBY3.3V RST SCL0CK 1 2 3 4 5 6 7 8 9 10 11 12 13 DG-BOARD (1/8) TNPA3756DJ TVRP178 TVRP177 TH-42PV65C DG-Board (1 of 8) Schematic Diagram TH-42PV65C DG-Board (1 of 8) Schematic Diagram 88 14.27.DG 电路板 （2/8）线路图 + + AO_A8 R_LED_STBY_LED GENX_R2 SDA0A AQ_D15 LVDS_PD GENX_G0 AO_A12 EXTRG0 GENX_R1 GENX_B1 SDA1 TRCD3 AP_WE MEMA10 KEY1 GENX_HIN GENX_R3 PSM_LEDR_AFC1_KEY2 AUDIO_MUTE AQ_D2 TRCST SCL0A SDATA AR_RAS AQ_D9 AO_A2 AQ_D4 AO_A19 GENX_G2 SCL2 AR_BA0 SCL1 AO_A5 AO_A14 AO_A1 AQ_D14 TRCD0 AGC1_TXD AGC2_RXD PANEL_SOS AP_OE AQ_D5 TRCD1 AR_UDQM SOUND_SOS AO_A3 SCL1 GENX_G3 SCLOCK AR_CKE AI_SENSOR AO_A17 SDA0B AQ_D10 GENX_B2 PANEL_STATUS AO_A16 TRCD2 AQ_D12 GENX_B0 GC_RST AR_LDQM AQ_D0 AO_A6 KEY3_KEY_EDGE AR_CLK AQ_D11 AQ_D7 AO_A10 RST QLINK_OUT_(SUB_SW1) ALL_OFF AQ_D8 SOS DISPEN GENX_R0 AQ_D3 ECO_ON SP_MUTE HDMI_DAC_PD AQ_D1 GENX_B3 FAN_MAX GENX_CLKIN GENX_VIN AR_WR AQ_D13 AO_A15 A_MON_MUTE_MSP_RESET AR_CAS FAN_SOS AP_CE RST AQ_D6 AO_A9 GENX_G1 GENX_R4 AO_A18 QLINK_IN2_(MAIN_SW2) AO_A7 AR_CS AO_A11 AO_A4 AO_A13 RM_IN MCU_RST TV_SUB_ON TV_SUB_ON SDA2 HPD2 QLINK_SEL_(SUB_SW2) HDMI_INT STB1.5V MCU_RST HDMI_5V_DET1 QLINK_IN1_(MAIN_SW1) AO_A0 HDMI_WP HPD1 HDMI_RST SCL0B GENX_B4 GENX_G4 GENX_G5 CVBS0 CVBS1 TV_MAIN_ON TV_MAIN_ON TRCCLK SDA1 DTV_BUS_CONNECT1 SRQ FORMAT_EDGE(MAIN) M_SDA0 PANEL_SDA1 PANEL_SCL1 GENX_YS GENX_YM STBY3.3V HDMI_A_MUTE HDMI_5V_DET2 HDMI_CEC PANEL_STBY_ON R1215 100 Q1143 B1ABDF000034 R1251 EXB2HV101JV R1177 100 Q1115 B1ABDF000034 C1156 50V 22p R1322 10 C1120 10V0.1u MAIN3.3V C1139 10V 0.1u R1225 22 R1207 100k C1168 10V 1u R1312 22 R1479 47k R1168 0 R1156 100k R1530 0 JS1102 0 R1275 7.15k R1174 100 C1127 10V 0.1u SUB3.3V R1331 100k R1310 22 R1234 0 R1199 47k R1153 100 R1228 22 C1150 10V 0.1u R1241 8.2k R1222 33 R1299 0 C1119 10V 0.1u R1220 68 R1316 10k Q1142 B1ABDF000034 R1238 47k R1330 47k C1158 10u 6.3V R1256 1k Q4918 B1ABDF000034 R1318 5.1k R1232 3.3k TP1107 R1132 100 C1190 16V 0.01u R1279 22 STBY5V R1159 12k R1236 2.7k R1224 47k C1149 10V 0.1u JS1100 0 R1281 1k R1332 100k R1301 0 R1175 56k R1147 EXB2HV560JV R1197 47k R1466 10k C1167 10V 1u D1107 MA2J72900L C0EBY0000041 IC1111 1 VIN 2 VSS 3 ON/OFF 5 VOUT 4 VDOUT R1252 EXB2HV101JV R1284 6.8k R1313 10k C1161 10V 1u JS1101 0 Q1141 B1ABDF000034 R1130 47k R1282 15k R1375 100k R1249 47k Q1108 B1ABDF000034 R1203 1k R1263 100 R1470 0 C1178 10V 1u R1325 100k R1155 4.7k R1154 4.7k R1218 68 C1137 10V 0.1u R1169 0 R1158 27k C1134 50V 15p R1376 27k R1183 EXB28V680JX R1149 EXB2HV680JV C1152 10V 0.1u C1145 10V 0.1u R1368 18k R1290 4.7k R1314 10k R1309 22 STBY3.3V SUB5V Q1110 B1CBHD000002 R1233 3.3k R1164 12k R1226 22 R1369 0 R1141 68 R1480 47k C1133 50V 15p Q1111 B1ABDF000034 R1389 0 R1307 100k R1327 68k C1155 16V 0.01u C1221 50V 1000p R1319 5.1k R1372 47k R1326 100k R1270 22 L1104 J0JHC0000078 R1280 22 R1146 270 R1239 12k R1311 22 R1221 3.3k C1146 10V 0.1u L1102 J0JHC0000078 Q1140 B1ABDF000034 R1324 82k R1151 100 R1135 10k Q1102 B1ABDF000034 R1321 15k C1160 6.3V 47u C1172 10V 0.1u R1410 1k R1269 0 X1100 H0J100500030 R1229 1.8k R1308 27k D1119 MA3X704A0L C1147 10V 0.1u R1200 EXB2HV680JV R1140 68 R1189 10k R1157 100 STBY3.3V C1131 10V 0.1u R1323 82k R1300 0 R1346 47k R1531 0 R1176 12k R1216 100 R1223 1k SUB5V Q1114 B1ABDF000034 C1132 10V 0.1u SUB5V R1187 EXB2HV680JV R1250 220k R1526 1k STBY3.3V Q1103 B1ABDF000034 R1231 47k Q1139 B1ABDF000034 C1162 16V 0.01u MN103SB20RGL IC1103 1 ZMEMD29 2 ZMEMD28 3 ZMEMD27 4 ZMEMD26 5 ZMEMD25 6 ZMEMD24 7 IVSS 8 - 9 - 10 - 11 - 12 - 13 - 14 - 15 - 16 IVDD 17 - 18 - 19 - 20 - 21 MVSS 22 MVDD 23 - 24 - 25 - 26 - 27 DQM0 28 DQM1 29 SDCKI 30 IVDD 31 SDCLK 32 IVSS 33 SDCKE 34 NSDWE 35 NSDCAS 36 NSDRAS 37 NSDCS 38 SDBS0 39 - 40 MEMA10 41 ZMEMA11 42 ZMEMA9 43 ZMEMA8 44 ZMEMA7 45 ZMEMA6 46 ZMEMA5 47 ZMEMA4 48 IVSS 49 IVDD 50 ZMEMA3 51 ZMEMA2 52 ZMEMA1 53 ZMEMA0 54 VSS 55 VDD 56 - 57 - 58 - 59 - 60 - 61 - 62 - 63 - 64 A17 65 A16 66 A15 67 A14 68 - 69 - 70 - 71 - 72 - 73 IVDD 74 IVSS 75 A20 76 A21 77 NWE0 78 A22 79 A19 80 A18 81 RTCCNT 82 - 83 - 84 - 85 IVSS 86 - 87 - 88 IVDD 89 - 90 - 91 - 92 A2 93 NRE 94 NCS0 95 ZA1 96 VSS 103 SCL1 104 NTEST 105 HSYNC 106 IVSS 107 OSDXI 108 IVDD 118 G04 119 G03 120 G02 121 - 122 - 123 B04 124 B03 125 B02 126 B01 127 IVSS 128 - 129 IVDD 130 - 131 - 132 SDA0A 133 SCL0A 134 VSS 135 RTCXI 136 RTCXO 137 VDD 138 RMIN_IRQ0 139 ROMCNT 140 TEST 141 AVSS1 142 CVBS0 143 AVDD1 144 VREFL0 145 VREFH0 146 VCMO0 147 IREF0 148 VCMO1 149 VREFH1 150 VREFL1 151 CVBS1 152 AVSS2 153 AVDD2 154 PVDD 155 CLL 156 CLH 157 PVSS 158 IVSS 159 - 160 - 161 - 162 - 163 ADIN4 164 ADIN5 165 CECINA 166 CECINB 167 IVSS 168 OSCXO 169 OSCXI 170 IVDD 171 TRCD3 184 - 185 - 186 - 187 - 188 - 189 - 190 - 191 IVDD 192 IVSS 193 - 194 - 195 - 196 - 197 - 198 - 199 - 200 - 201 IVDD 202 IVSS 203 MVSS 204 MVDD 205 - 206 - 207 - 208 - 209 - 210 - 211 - 212 - 213 IVSS 214 IVDD 215 ZMEMD31 216 ZMEMD30 109 - 111 YSOUT 113 R03 115 R01 117 G05 110 - 112 R04 114 R02 116 - 172 TRCD2 173 TRCD1 174 TRCD0 181 VSS 182 VDD 183 - 97 NRST 98 VDD 99 PSCNT 100 SDA2 101 SCL2 102 SDA1 175 TRCST 176 TRCCLK 177 EXTRG1 178 EXTRG0 179 SDATA 180 SCLOCK R1367 33k R1184 0 R1165 15k R1363 47k R1271 22 MAIN3.3V Q1109 B1CBHD000002 SUB3.3V R1302 0 R1214 10k STBY3.3V C1157 50V 22p PA1101 K5H8012A0023 C1141 10V 0.1u C1138 10V 0.1u R1283 100 R1264 100 R1448 47k Q1101 B1ABDF000034 C1128 10V 0.1u R1329 47k SUB9V STBY5V R1181 100 R1240 47k C1144 10V 0.1u R1148 EXB2HV560JV Q1116 B1ABDF000034 R1344 100 C1121 10V 0.1u R1384 100 R1131 100 R1478 68 X1101 H0J327200114 TP1106 L1103 J0JHC0000078 C1129 10V 0.1u D1106 MA2J72900L Q1113 B1ABDF000034 C1142 10V 0.1u R1449 47k R1134 1k C1177 10V 0.33u R1246 9.1k C1148 10V 0.1u Q4919 B1ABDF000034 C1153 4V 100u R1315 33k C1154 10V 0.1u C1135 10V 0.1u MAIN3.3V C1125 10V 0.1u C1140 10V 0.1u SUB3.3V C1122 10V 0.1u R1188 10k STBY5V D1121 MA2J72900L R1467 47k R1243 1k R1182 68k R1217 100 R1235 2.7k C1159 10V 0.1u C1136 10V 0.1u R1451 47k STBY5V R1328 68k C1118 10V 0.1u R1411 4.7k Q1100 B1ABDF000034 R1133 1k C1123 10V 0.1u C1130 10V 0.1u R1230 22 C0CBCAD00016 IC1110 1 Vcont 2 GND 3 Np 5 Vin 4 Vout MCU_ANALOG_VIDEO YMOUT0 MEMD5/D5/IRQ6A STB5V(SUB5V BACKUP) HOUTA A4/MEMA1 ADIN3 ADIN1 MEMD28/D28 MEMD6/D6/IRQ7A A10/MEMA7 ADIN0 SCL0B MEMD19/D19 MEMD30/D30 ZMEMD20/IRQ5B ZMEMD18/IRQ3B MEMD10/D10 MEMD20/D20 G01 A11/MEMA8 STB5V MEMD8/D8 SUB5V A7/MEMA4 A8/MEMA5 ZMEMD21/IRQ6B ZMEMD23/IRQ8B MEMD29/D29 MEMD7/D7/IRQ8A (USA:KEYSCAN3) (Euro:key EDGE) MEMD27/D27 SDBS1/A1 VSYNC MEMD25/D25 MEMD31/D31 MEMD16/D16 ZMEMD19/IRQ4B SDA0B ZMEMD22/IRQ7B A6/MEMA3 B00 MEMD17/D17 G00 MEMD18/D18 MEMD21/D21 MEMD11/D11 VCLKOUTA ADIN2 MEMD24/D24 A5/MEMA2 A9/MEMA6 R00 MEMD22/D22 MEMD1/D1/IRQ2A ZMEMD16/NCS2B MEMD23/D23 MEMD4/D4/IRQ5A MEMD0/D0/NCS2A ZMEMD17/IRQ2B MEMD26/D26 MEMD15/D15 MEMD2/D2/IRQ3A MEMD14/D14 MEMD3/D3/IRQ4A A12/MEMA9 MEMD13/D13 A13/MEMA11 MEMD9/D9 MEMD12/D12 A3/MEMA0 14 11 13 17 12 18 15 16 10 MAIN MICOM RESET STB 3.3V STB 1.5V 2 4 3 1 11 8 6 5 13 12 9 10 7 21 22 22a 23 24 25 26 27 28 29 30 DG-BOARD (2/8) TNPA3756DJ TH-42PV65C DG-Board (2 of 8) Schematic Diagram TH-42PV65C DG-Board (2 of 8) Schematic Diagram R1152 1k R1191 47k R1186 47k R1129 47k R1340 47k R1162 47k R1160 47k R1452 47k 89 14.28.DG 电路板 （3/8）线路图 + + + + + + NP NP + CVBS0 CVBS1 AGC1_SD_TXD AGC2_SD_RXD AGC1_TXD AGC2_RXD AUDIO_MUTE RST A_MON_MUTE_MSP_RESET SDA0B SCL0B HDMI_L HDMI_R PC_R PC_G PC_B PC_HS PC_VS RGB_FB RGB_CVBS MAIN_PR MAIN_Y/CVBS MAIN_PB/C BS_Y(V) MAIN_R MAIN_L BS_SL BS_SR SP_MUTE TV_MAIN_ON TV_SUB_ON SOS SOUND_SOS SL SL_GND SR SR_GND SL SL_GND SR SR_GND SOS AD_DAT AD_BICK AD_LRCK D_STB3R3V D_IIC_CONT D_SCL2 D_SDA2 D_TXD D_RXD D_IIC_INT AGC1_SD_TXD AGC2_SD_RXD SCL0A SDA0A SDA2 SCL0B SDA0B SCL1 SDA1 SRQ AFC2_AFT2_SUB-MUTE PSM_LEDR_AFC1_KEY2 AI_SENSOR KEY1 RM_IN G_LED_POWER R_LED_STBY_LED AGC2_SD_RXD AGC1_SD_TXD DTV_SCL0B DTV_SDA0B KEY3_KEY_EDGE FAN_SOS R_LED G_LED RIMOCON D_PSTB D_PBUSY D_PDB0 D_PSLCT D_PDB1 D_15V ODU_ON_ACTIVE_STB_LED SCL2 EURO_TEXT FAN_MAX D1117 B0BC3R5A0163 MAIN1.8V C1230 47u 16V STBY3.3V C1234 47u 16V R1441 0 TP1118 DG20 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 SUB9V TP1117 TP1120 R1179 100 DG1 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60 61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80 STBY5V L1109 J0JHC0000078 Q1135 B1ABDF000034 R1178 100 TP1116 SUB5V R1428 0 R1475 270 C1233 47u 16V C1212 50V 150p MAIN9V DG2 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 R1212 0 Q1130 B1ABDF000034 R1352 47k C1209 10V 1u R1426 0 R1432 0 R1474 0 R1379 330 TP1113 R1427 0 C1231 47u 16V SUB3.3V R1429 0 R1554 0 R1556 330 JS1117 R1555 0 C1232 47u 16V R1351 100 R1333 100 JS1109 C1229 47u 16V R1431 0 STBY5V R1377 0 C1219 16V 10u R1447 470 C1220 16V 10u TP1119 DG15 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 C1228 47u 16V R1461 0 R1462 0 R1491 0 R1439 270 R1472 300 R1436 560 R1430 0 C1294 50V 33p Q1131 B1ABDF000034 MAIN3.3V R1437 560 SUB9V R1473 300 R1354 100 TP1115 Q1134 B1ABDF000034 R1446 470 MAIN5V TP1114 BT30V MAIN1.8V SOUND_SOS MAIN9V SUB5V BT30V MAIN1.8V ODU_ON/OFF SUB9V SUB9V TV_MAIN_ON SUB3.3V SOS MAIN5V MAIN3.3V TUNER_SUB_ON SCL1(Main3.3V) SDA1(Main3.3V) 20 19 23 24 26 25 22 27 21 MAIN5V SUB5V SUB9V BT30V (HC15) HC-BOARD TO D_PSLCT D_PDB1 D_IIC_CONT D_TXD REMOCON D_STB3R3V D_PSTB D_BUSY G_LED D_RXD D_SCL2 D_PDB0 D_SDA2 R_LED D_IIC_INT STBY5V SDA2 SCL2 SDA1 SCL1 SCL0B SDA0B SDA0A SRQ D_15V SCL0A DTV_EEP_SDA0B DTV_EEP_SCL0B SD_RX SD_TX SD_TX SD_RX SD_IRQ SD_RST STBY_LED G_LED RM_IN KEY1 AI_SENSOR KEY3_KEY_EDGE AFC1 AFC2 ACTIVE_STB_LED H-BOARD TO (H2) (PA20) PA-BOARD TO (H1) H-BOARD TO SUB3.3V SR SR SL SL MAIN_Y SR SL SUB_PR SUB_PB SUB_Y HDMI_L HDMI_R BS_Y(V) BS_SR BS_SL MAIN_R MAIN_L PC_VS PC_HS PC_B PC_G PC_R MAIN_PB/C MAIN_Y/CVBS MAIN_PR RGB_CVBS RGB_FB AUDIO_MUTE QLINK_AV2 SP_MUTE RST QLINK_AV3 SCL0B A_MON_MUTE_ SOS SDA0B AD_DAT AD_LRCK AD_BICK MSP_RESET FAN_SOS FAN_MAX MAIN3.3V MAIN3.3V 51 52 53 54 55 56 57 58 59 DG-BOARD (3/8) TNPA3756DJ TH-42PV65C DG-Board (3 of 8) Schematic Diagram TH-42PV65C DG-Board (3 of 8) Schematic Diagram 21 22 22a 23 24 25 26 27 28 29 30 QLINK_IN1_(MAIN_SW1) QLINK_IN2_(MAIN_SW2) R1382 0 R1383 0 90 14.29.DG 电路板 （4/8）线路图 + + + + Thermal Pad JTAG_GC5_BA JTAG_TMS JTAG_BA_FS UVIN0 RIN3 UVIN1 RIN2 YIN5 UVIN7 RIN1 YIN4 UVIN6 RIN0 YIN3 UVIN5 YIN6 UVIN2 UVIN4 PC_HS CLKOA PC_VS PC_B CLKIA SCL2 YIN2 SDA2 YIN0 UVIN9 YIN1 UVIN8 PC_G HSIA PC_R YIN7 YIN8 VSIA YIN9 REFCK_ADV MAIN_Y/CVBS MAIN_PB/C EURO_TEXT MAIN_PR TV_MAIN_ON RGB_CVBS JTAG_FS_GC5 JTAG_BA_FS GC_RST UVIN3 JTAG R4481 2.2k C4193 50V 1000p R4488 2.2k R4495 43k C4544 16V 1u C4168 50V 68p R4503 160 MAIN5V C4199 16V 0.01u MAIN9V R4004 0 C4208 10V 0.1u L4023 J0JHC0000078 R4577 2.2k C1AB00002456 IC4019 1 P32 2 P31 3 INT 4 CS/HS 5 DGND 6 DVDDIO 7 P15 8 P14 9 P13 10 P12 11 DGND 12 DVDD 13 P29 14 P28 15 SFL/SYNC_OUT 16 SCLK2 17 DGND 18 DVDDIO 19 SDA2 20 P11 21 P10 22 P9 23 P8 24 P27 25 P7 26 P6 27 P5 28 P4 29 P26 30 R_ACTIVE/P25 31 SRLIN/P24 32 SRLUP/P23 33 TRGIN/P22 34 P21 35 MEI_CK/DCLK_IN 36 BLC/LLC1 37 XTAL1 38 XTAL 39 DVDD 40 DGND 41 P3 42 P2 43 P1 44 P0 45 P20 46 ELPF 47 PVDD 48 PVDD 49 AGND 50 AGND 51 FB 52 SOG 53 AIN7 54 AIN1 55 AIN8 56 AIN2 57 AIN9 58 AIN3 59 ELPF2 60 AGND 61 CAPY1 62 CAPY2 63 AVDD 64 REFOUT 65 CML 66 AGND 67 BIAS 68 CAPC1 69 CAPC2 70 TEST0 71 AIN10 72 AIN4 73 AIN11 74 AIN5 75 AIN12 76 AIN6 77 SOY 78 RESET 79 DE_IN 80 ALSB 81 SDA 82 SCLK 83 P40 84 P39 85 VS_IN 86 HS_IN 87 P38 88 P37 89 DGND 90 DVDD 91 P19 92 P18 93 P17 94 P16 95 P36 96 P35 97 P34 98 FIELD/DE 99 VS 100 P33 R4527 22 TP4030 C4172 16V 0.1u Q4063 B1ABDF000034 C4158 10V 1u C4160 10V 0.1u Q4053 B1ABDF000034 Q4056 2SA207700L C4218 50V 1000p R4480 422 Q4064 B1ABDF000034 C0CBCAC00275 IC4016 1 VDD 2 GND 3 CE 5 VOUT 4 NC C4253 47u 6.3V R4517 1.37k R4024 0 R4019 0 C4217 16V 0.1u R4568 100 TP4028 C4216 47u 6.3V C4195 16V 0.1u C4178 16V 0.039u R4498 1k R4492 1k C4211 10V 0.1u R4572 10k R4552 EXB28V220JX R4533 22 R4474 1.21k Q4061 B1ABDF000034 C4215 10V 0.1u C4224 10V 0.1u C4180 16V 0.1u C4273 10V 0.1u R4550 EXB28V220JX MAIN3.3V C4200 47u 6.3V C4201 16V 0.01u R4578 2.2k Q4059 2SA207700L C4171 50V 470p L4073 J0JHC0000078 R4565 22 R4465 220k JS4017 C4227 16V 0.082u Q4058 2SA207700L R4487 560 C4186 6.3V 10u SUB5V C4262 10V 0.1u C4235 16V 0.01u C4248 10V 0.1u R4564 22 R4560 EXB28V220JX R4561 EXB28V220JX JS4111 0 L4029 J0JHC0000078 C4196 16V 0.1u C4219 10V 1u R4521 22 R4500 27k R4522 22 JS4023 0 R4479 422 C4245 10V 0.1u R4520 1.69k R4470 150 R4508 0 R4507 0 R4490 1k R4555 EXB28V220JX C0CBCAC00275 IC4018 1 VDD 2 GND 3 CE 5 VOUT 4 NC C4165 10V 0.1u C4244 10V 1u R4501 1k C4263 10V 0.1u C4177 16V 0.68u JS4024 0 R4482 1.78k R4483 1.78k C4228 16V 0.01u C4185 6.3V 10u R4008 0 C4191 10V 0.1u C4269 10V 1u R4554 22 L4038 J0JHC0000078 R4499 1k C4256 10V 1u C4264 10V 0.1u C4188 10u 6.3V R4486 487 R4025 0 C4194 16V 0.1u Q4062 B1ABDF000034 R4534 100 R4579 2.2k C4197 16V 0.1u C4206 16V 0.1u MAIN1.8V SUB9V Q4055 2SA207700L R4575 4.7k L4031 J0JHC0000078 R4001 1.21k TP4029 R4563 22 Q4057 2SA207700L C4175 16V 0.1u R4510 0 R4496 1k R4544 22 R4469 150 C4173 16V 0.1u MAIN3.3V Q4050 B1ABDF000034 C4266 16V 0.01u JS4016 C4176 6.3V 2.2u C4189 10V 0.1u C4190 10V 0.1u R4457 0 C4159 16V 0.1u C4543 16V 0.1u C4209 10V 0.1u R4502 1k R4535 100 C4204 10V 0.1u JS4022 0 C4272 47u 6.3V IC4013 C0CBCBF00009 1 VOUT 2 NC 3 GND 4 CN 5 CONT 6 NC 7 NC 8 VIN C4205 16V 0.1u R4497 1k C4174 10V 0.1u 1.8V Y PR RGB_CVBS PB/C SYS_RST(L_3.3V) 33 36 28 32 31 30 29 34 35 10bit A/D(ADV7499) AD 3.3V AVR 1.8V AVR 1.8V 72 73 74 75 77 78 51 52 53 54 56 57 58 59 55 76 71 DG-BOARD (4/8) TNPA3756DJ TH-42PV65C DG-Board (4 of 8) Schematic Diagram TH-42PV65C DG-Board (4 of 8) Schematic Diagram 91 14.30.DG 电路板 （5/8）线路图 Thermal Pad + + + + + SCL1 HPD1 HDMI_DAC_PD UBIN3 UBIN2 UBIN9 YBIN6 UBIN0 HDMI_RST YBIN2 UBIN7 YBIN4 HDMI_5V_DET2 HDMI_5V_DET2 UBIN6 HDMI_5V_DET1 HDMI_5V_DET1 VSIB AP_DE SDA1 YBIN3 UBIN1 HSIB YBIN7 YBIN0 UBIN5 YBIN9 UBIN4 UBIN8 REFCK_HDMI YBIN5 HPD2 YBIN8 DDC_SDA0 DDC_SCL0 YBIN1 CLKINB2 HDMI_R HDMI_L HDMI_CEC HDMI_WP HDMI_INT JS4025 100 C4332 1u 10V C4305 1u 10V C4327 0.1u 10V R4677 18k D4021 EZJZ0V80008B R4630 4.7k L4046 J0JHC0000078 R4600 2.7 L4076 J0JHC0000078 TP4032 C4317 0.1u 10V D4033 EZJZ0V80008B C4347 1u 10V R4642 22 C4342 0.1u 10V C4306 1u 10V D4036 EZJZ0V80008B C4346 0.1u 10V R4599 2.7 R4634 22 C0FBBK000047 IC4025 1 MCLK 2 BICK 3 SDTI 4 LRCK 5 PDN 6 SMUTE/CSN 7 ACKS/CCLK 8 DIF0/CDTI 9 P/S 10 AOUTR 11 AOUTL 12 VCOM 13 VSS 14 VDD 15 DZFR 16 DZFL C1AB00002535 IC4026 1 DE 2 HSYNC 3 VSYNC 4 IOGND 5 IOVCC 6 NC 7 NC 8 NC 9 EVNODD 10 NC 11 NC 12 NC 13 NC 14 NC 15 IOGND 16 IOVCC 17 NC 18 NC 19 NC 20 NC 21 CGND 22 CVCC18 23 CVCC18 24 CGND 25 IOGND 26 IOVCC 27 CSDA 28 CSCL 29 DSDA1 30 DSCL1 31 DSDA0 32 DSCL0 33 R1PWR5V 34 R0PWR5V 35 CVCC18 36 CGND 37 PVCC0 38 AVCC 39 R0XC- 40 R0XC+ 41 AGND 42 AVCC 43 R0X0- 44 R0X0+ 45 AGND 46 AVCC 47 R0X1- 48 R0X1+ 49 AGND 50 AVCC 51 R0X2- 52 R0X2+ 53 AGND 54 TMDSPGND 55 PVCC1 56 RSVD_A 57 AVCC 58 R1XC- 59 R1XC+ 60 AGND 61 AVCC 62 R1X0- 63 R1X0+ 64 AGND 65 AVCC 66 R1X1- 67 R1X1+ 68 AGND 69 AVCC 70 R1X2- 71 R1X2+ 72 AGND 73 CGND 74 CVCC18 75 IOGND 76 IOVCC 77 MUTEOUT 78 SPDIF 79 CVCC18 80 CGND 81 NC 82 NC 83 NC 84 SD0 85 WS 86 SCK 87 NC 88 MCLK 89 IOVCC 90 IOGND 91 CGND 92 CVCC18 93 NC 94 AUDPVCC18 95 AUDPGND 96 XTALOUT 97 XTALIN 98 XTALVCC 99 REGVCC 100 NC 101 RSVDL 102 RESET# 103 SCDT 104 INT 105 CVCC18 106 CGND 107 CLK48B 108 IOGND 109 IOVCC 110 Q23 111 Q22 112 Q21 113 Q20 114 CVCC18 115 CGND 116 Q19 117 Q18 118 Q17 119 Q16 120 IOGND 121 ODCK 122 IOVCC 123 Q15 124 Q14 125 Q13 126 Q12 127 CGND 128 CVCC18 129 Q11 130 Q10 131 Q9 132 Q8 133 Q7 134 IOVCC 135 IOGND 136 Q6 137 Q5 138 CGND 139 CVCC18 140 Q4 141 Q3 142 Q2 143 Q1 144 Q0 C4314 0.1u 10V C4311 0.1u 10V IC4023 1 E0 2 E1 3 E2 4 VSS 5 SDA 6 SCL 7 WC 8 VCC R4620 56 R4640 22 R4601 2.7 C4315 6.3V 10u R4644 22 TP4033 R4609 10k R4675 18k R4603 2.7 R4621 47k R4606 10k C4284 0.1u 10V JS4026 100 R4637 33 C4331 6.3V 10u C4281 0.1u 10V Q4068 B1ABDF000034 C4349 16V 0.01u D4048 MAZ30560ML L4048 J0JHC0000078 C0DBFFD00003 IC4027 1 2 3 4 5 6 7 D4028 EZJZ0V80008B D4041 EZJZ0V80008B Q4071 B1MBACA00008 G1 D1 S1 G2 D2 S2 D4026 EZJZ0V80008B L4043 J0JHC0000078 R4624 56 D4030 EZJZ0V80008B D4045 EZJZ0V80008B D4027 EZJZ0V80008B R4641 EXB28V330JX C4325 0.1u 10V D4052 B0HCMM000014 C4321 0.1u 10V MAIN3.3V C4337 0.1u 10V D4050 B0HCMM000014 TP4066 L4049 J0JBC0000080 L4075 J0JHC0000078 L4040 J0JHC0000078 R4658 22 C4298 1u 10V R4617 4.7k R4629 4.7k C4334 0.1u 10V C4302 1u 10V C4292 0.1u 10V R4619 47k C4322 0.1u 10V C4282 0.1u 10V R4286 0 R4605 10k IC4022 1 E0 2 E1 3 E2 4 VSS 5 SDA 6 SCL 7 WC 8 VCC R4584 39 L4052 J0JCC0000077 TP4031 R4679 22k D4047 MAZ30560ML TP4034 R4589 2.7 L4045 J0JHC0000078 R4610 10k R4645 22 Q4084 B1ABDF000034 C4348 16V 47u C4300 1u 10V C4338 0.1u 10V D4038 EZJZ0V80008B R4596 2.7 R4595 2.7 D4044 EZJZ0V80008B R4593 2.7 R4662 22 R4628 10k C4026 0.1u 10V R4027 1k R4673 10k R4636 10k R4045 0 C4340 470p 50V C4304 1u 10V L4078 J0JHC0000078 C4333 0.1u 10V C4318 0.1u 10V D4023 EZJZ0V80008B C4335 0.1u 10V R4672 10k R4271 0 Q4069 B1ABDF000034 R4680 22k R4590 2.7 C4309 0.1u 10V L4071 J0JBC0000080 Q4083 2SK122800L D4019 EZJZ0V80008B C4354 0.01u 16V C4287 0.1u 10V R4602 2.7 R4622 56 D4037 EZJZ0V80008B R4681 33k R4101 10k R4631 4.7k C4339 2.2u 6.3V JS4104 R4643 22 R4639 10k C4312 0.01u 16V D4024 EZJZ0V80008B D4031 EZJZ0V80008B Q4066 B1ABDF000034 C4297 0.1u 10V D4025 EZJZ0V80008B TP4065 C4336 0.1u 10V R4665 EXB2HV220JV C4345 10u 6.3V R4607 22 C4288 0.1u 10V D4032 EZJZ0V80008B TP4036 C4310 0.01u 16V 33u 6.3V C4289 R4604 2.7 C4307 0.1u 10V D4035 EZJZ0V80008B D4034 EZJZ0V80008B R4661 4.7k R4618 4.7k R4682 33k C4343 16V 10u R4667 EXB2HV220JV C4541 0.1u 10V R4613 4.7k R4026 1k Q4082 2SK122800L C4352 50V 33p R4591 2.7 R4598 2.7 IC4028 C0ABBB000230 1 2 3 4 5 6 7 8 R4031 10k R4010 0 L4044 J0JHC0000078 C4296 6.3V 10u C4316 0.1u 10V R4594 2.7 R4626 56 DG9 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 C4313 0.1u 10V TP4064 D4029 EZJZ0V80008B 33u 6.3V C4290 Q4065 B1ABDF000034 R4592 2.7 MAIN5V C4330 0.1u 10V R4597 2.7 C4283 0.1u 10V R4668 68 L4041 J0JHC0000078 R4648 33 R4657 1.8k L4050 J0JHC0000078 R4655 33 C4329 0.1u 10V R4040 0 C4350 50V 180p L4051 J0JHC0000078 R4583 39 C4344 10u 6.3V R4647 22 C4353 50V 33p L4042 J0JHC0000078 C4351 50V 180p R4669 EXB2HV220JV C4303 1u 10V D4020 EZJZ0V80008B TP4035 R4633 22 Q4067 B1ABDF000034 C4301 1u 10V R4632 4.7k D4051 B0HCMM000014 MAIN9V C4308 0.1u 10V R4612 4.7k Q4070 B1MBACA00008 G1 D1 S1 G2 D2 S2 C4291 0.1u 10V C4320 0.1u 10V R4660 22 D4022 EZJZ0V80008B D4049 B0HCMM000014 C4299 1u 10V C4341 16V 47u DG8 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 R4032 10k R4272 0 MAIN1.8V MAIN3.3V DDCG CEC D0+ CLKG D2- DDCG CEC D2+ GND +5V Cn D0+ CLK+ D0G D1- HDMI_SCL D1+ D2G L CLKG HDMI_SDA HDMI_Y0 HDMI_Y1 - HDMI_Y2 N.C. R D2- HPDT D1G HDMI_Y3 D0- HDMI_Y4 +5V HDMI_Y5 + - SDA SCL CLK- HDMI_UV0 HDMI_UV2 NC HDMI_Y6 D1G HDMI_UV6 HDMI_Y7 HDMI_CLK RX_MCLK RX_SCK R AUDIO DAC RX_WS HDMI_L_AUDIO + VIL < 0.8V HDMI_R_AUDIO SDA Vin sub L SCL HDMI_UV4 CLK- HDMI_UV3 CONT RX_SD0# HDMI_UV5 DIGITAL VIDEO SIGNAL (HDMI) Vo VIH > 2.2V HDMI_UV1 HDMI_UV7 D0- HIGH:MUTE HDMI_VS HDMI_DE HDMI_HS D2+ N.C. CLK+ HPDT D0G D1- D1+ D2G G D S D 43 44 38 42 37 41 45 39 40 G S HDMI I/F RECEIVER EEPROM EEPROM AUDIO AMP HDMI IN 1 HDMI IN 2 MAIN 1.8V 92 93 94 95 96 97 72 73 74 76 77 78 75 71 91 TVRN917 TVRN916 DG-BOARD (5/8) TNPA3756DJ TH-42PV65C DG-Board (5 of 8) Schematic Diagram TH-42PV65C DG-Board (5 of 8) Schematic Diagram 92 14.31.DG 电路板 （6/8）线路图 + A_DDR_DQ2 CLKIA PEAKS-CIN6 A_DDR_DQ18 YBIN2 A_DDR_DQ1 VSIA CLKINB PEAKS-CIN2 GENX_HIN A_DDR_DQ17 A_DDR_DQ0 YBIN4 CLKOA PEAKS-CIN5 UVIN0 A_DDR_DQ16 A_DDR_DQ19 YBIN7 PEAKS-CIN4 YIN1 A_DDR_DQ20 PEAKS-CIN7 RIN1 AP_DE A_DDR_DQ21 PEAKS-YIN0 UVIN1 VSIB A_DDR_DQ22 HSIA UVIN3 GENX_YS PEAKS-YIN1 A_DDR_RAS RIN0 YBIN1 HSIB RIN2 YIN9 A_DDR_WE PEAKS-YIN2 A_DDR_DQ23 YIN0 YBIN6 UBIN3 UVIN9 A_DDR_BA0 PEAKS-YIN3 RIN3 YBIN9 A_DDR_BA1 UBIN2 PEAKS-YIN4 YIN3 PEAKS-YIN5 YBIN5 UBIN7 YIN7 REFCK_ADV A_DDR_DQ25 PEAKS-YIN6 A_DDR_A8 UVIN6 A_DDR_DQ26 PEAKS-YIN7 YIN6 A_DDR_A7 JTAG_TRST A_DDR_NCLK A_DDR_DQ27 A_DDR_A5 YIN2 JTAG_TCK A_DDR_CLK A_DDR_DQ28 A_DDR_A6 A_DDR_DQ10 UBIN1 UVIN7 A_DDR_DQS1 A_DDR_DQ9 JTAG_TMS A_DDR_A1 REFCK_HDMI A_DDR_DQ29 A_DDR_DQS3 UBIN9 YIN5 A_DDR_A9 A_DDR_DQ30 A_DDR_DQS2 JTAG_FS_GC5 UVIN2 UBIN6 A_DDR_DQ8 A_DDR_A2 A_DDR_SDCKE UVIN4 PEAKS-CLKIN UBIN4 A_DDR_DQ15 A_DDR_A0 A_DDR_DQ24 A_DDR_CAS PEAKS-HIN A_DDR_DQ3 A_DDR_A4 UBIN8 A_DDR_DQ31 PEAKS-VIN A_DDR_A3 A_DDR_DQS0 A_DDR_DQ4 UBIN0 A_DDR_DQ14 UVIN5 A_DDR_A11 A_DDR_DQ5 UBIN5 A_DDR_DQ13 A_DDR_A10 UVIN8 A_DDR_DQ6 A_DDR_DQ12 YBIN0 GENX_CLKIN PEAKS-CIN0 YIN8 A_DDR_DQ11 YBIN3 CLKINB2 PEAKS-CIN1 A_DDR_DQ7 YIN4 YBIN8 PEAKS-CIN3 GENX_VIN GENX_YM GENX_B0 GENX_G3 GENX_R2 GENX_B2 GENX_R1 GENX_R0 GENX_R3 GENX_B1 GENX_B3 GENX_G1 GENX_G4 GENX_G0 GENX_G2 JTAG_GC5_BA GENX_G5 GENX_R4 GENX_B4 IC4037 C30 UVIC0 IC4037 F30 CLKIC IC4037 A24 OSDYSI IC4037 A3 THQHOUT 1000p 50V C4414 IC4037 C17 OSDI15 IC4037 A17 CLKOD2 IC4037 AE5 AVSSCK IC4037 AK9 WE IC4037 R27 GND IC4037 K1 FRCKO3 IC4037 AF10 VDD25 IC4037 R13 GND IC4037 C18 OSDI12 IC4037 D28 UVIC1 IC4037 AB3 VDD25 IC4037 K4 YIB9 IC4037 T3 RVIA5 IC4037 AJ1 VDD25 IC4037 P16 GND IC4037 B24 OSDYMI 0.1u 10V C4397 IC4037 AE27 VDD12 IC4037 R12 GND IC4037 D18 GND IC4037 AD4 GND IC4037 R26 GND IC4037 AG3 DQ11 JS4029 220 IC4037 AJ20 GND IC4037 C28 GND IC4037 T16 VDD12 IC4037 A28 YIC4 IC4037 E10 GND IC4037 A4 THQCO7 IC4037 AH4 VREFSSTL2V_0 IC4037 R1 BUIA5 IC4037 AK29 GND IC4037 A6 THQYO9 IC4037 G5 GND IC4037 AE2 DQ24 IC4037 AG27 VDD12 0.1u 10V C4407 IC4037 U15 GND IC4037 A2 CLKOTHQ1 IC4037 C13 FHQCIN8 IC4037 B19 OSDI10 IC4037 T4 GND IC4037 V12 VDD25 IC4037 A5 THQCO3 IC4037 AJ5 A5 IC4037 AF4 GND IC4037 A18 OSDI14 0.1u 10V C4408 IC4037 AE4 GND IC4037 E22 GND IC4037 T5 GND IC4037 F2 UVIB5 IC4037 K3 HSIB IC4037 AF25 GND IC4037 A20 OSDI8 0.1u 10V C4389 IC4037 L1 BUIA1 IC4037 V2 GYIA2 IC4037 D29 UVIC2 C4362 6.3V 10u IC4037 D30 UVIC3 IC4037 B12 FHQYIN2 IC4037 AG8 GND C4367 10V 0.1u IC4037 D16 MOSDVSO2 IC4037 D25 TCK IC4037 AC1 DQ29 IC4037 G1 YIB0 0.1u 10V C4404 IC4037 AH7 A3 IC4037 AF15 GND IC4037 H1 YIB4 IC4037 A22 OSDI2 IC4037 AB1 DQ31 IC4037 W27 GND IC4037 N1 RVIA2 IC4037 R15 VDD12 IC4037 AK3 SDCLKO IC4037 J1 YIB8 IC4037 R16 GND IC4037 C16 FRCKO2 IC4037 AJ26 GND IC4037 N2 RVIA1 IC4037 AF24 GND IC4037 Y3 GYIA5 IC4037 AF14 AVSS_DDR IC4037 AC3 DQ28 IC4037 Y2 GYIA6 IC4037 AK11 DQS2 IC4037 P15 GND IC4037 E21 GND IC4037 L3 CLKIA2 R4037 EXB2HV103JV IC4037 AF7 VDD25 IC4037 B15 FHQCIN3 IC4037 P13 VDD12 IC4037 J3 YIB6 IC4037 B4 THQCO8 IC4037 D22 GND IC4037 B17 MOSDHSO2 IC4037 V15 GND 1000p 50V C4403 IC4037 R2 BUIA4 0.1u 10V C4398 IC4037 AJ28 GND 1u 10V C4400 IC4037 A14 FHQCIN7 IC4037 C12 FHQYIN1 IC4037 J2 YIB7 C4003 6.3V 10u 1000p 50V C4385 IC4037 F6 GND IC4037 V1 GYIA3 IC4037 B20 OSDI7 IC4037 E14 GND IC4037 A21 OSDI5 IC4037 C7 THQYO7 IC4037 P18 GND R4713 EXB2HV221JV IC4037 M12 VDD12 IC4037 AG12 GND IC4037 H2 YIB3 IC4037 C15 FHQCIN2 IC4037 D6 THQCO2 IC4037 D24 TDI R4711 10k IC4037 V18 VDD12 IC4037 D5 THQCO6 IC4037 AK17 GND IC4037 J5 GND R4727 0 IC4037 AJ9 RAS IC4037 V17 GND IC4037 B21 OSDI4 IC4037 AG15 GND IC4037 C1 ENBIB IC4037 AF6 AVDCLK IC4037 E3 UVIB1 IC4037 N17 GND IC4037 U5 GND IC4037 AJ11 DQ21 IC4037 D26 TDO MAIN1.2V IC4037 Y27 GND IC4037 AH20 GND IC4037 D3 VDD12 IC4037 A26 CLKOD IC4037 G28 GND IC4037 F29 HSIC IC4037 B27 YIC6 IC4037 D1 UVIB0 IC4037 C10 FHQYIN7 IC4037 D10 GND IC4037 D8 THQYO4 IC4037 U2 RVIA7 IC4037 J4 YIB5 IC4037 E30 UVIC7 IC4037 AC5 AVSS_DDR IC4037 W26 GND IC4037 N5 GND IC4037 T1 BUIA7 IC4037 D2 CLKIB2 1u 10V C4373 IC4037 AJ6 A4 IC4037 AG25 GND IC4037 AD3 DQ26 IC4037 AK30 VDD12 IC4037 B1 VDD12 IC4037 AF11 VDD25 1000p 50V C4413 IC4037 T15 GND IC4037 T12 GND IC4037 AJ4 CKE R4709 68 1000p 50V C4406 IC4037 AG11 VDD25 IC4037 E27 UVIC4 1000p 50V C4393 IC4037 AJ29 VDD12 IC4037 C3 GND IC4037 AJ12 DQ18 IC4037 C8 THQYO3 IC4037 AH16 DQ0 0.1u 10V C4384 IC4037 P17 GND JS4028 0 IC4037 AG16 GND IC4037 AH1 DQ8 IC4037 M4 GND L4053 J0JHC0000078 1000p 50V C4383 IC4037 B11 FHQYIN5 1000p 50V C4390 IC4037 E18 GND IC4037 F1 UVIB6 IC4037 AH15 DQ3 IC4037 AG22 GND IC4037 AD5 GND 0.1u 10V C4377 IC4037 A7 THQYO5 IC4037 B23 OSDHSI IC4037 AF9 GND IC4037 AH12 DQ19 IC4037 B7 THQYO6 IC4037 W1 GYIA4 IC4037 AK13 GND IC4037 K2 VSIB IC4037 AK4 A8 IC4037 T19 VDD12 IC4037 N4 GND IC4037 AC2 DQ30 C4004 6.3V 10u IC4037 T2 BUIA6 IC4037 AG4 GND IC4037 V3 GYIA1 IC4037 AJ8 A0 1u 10V C4391 IC4037 B9 FHQVIN IC4037 C9 FHQHIN IC4037 R14 GND R4039 EXB2HV103JV IC4037 U16 GND IC4037 A13 FHQYIN0 IC4037 AH26 GND R4041 0 IC4037 AF23 GND IC4037 A30 GND 1u 10V C4399 IC4037 AA2 VDD25 IC4037 C22 OSDI0 IC4037 AH21 GND IC4037 E1 UVIB2 IC4037 D17 GND R4898 10k IC4037 N16 GND IC4037 AG23 GND 0.1u 10V C4364 IC4037 AK10 DQ22 IC4037 AF16 GND IC4037 D7 THQYO8 IC4037 AF12 GND IC4037 AG6 VDD25 C4014 6.3V 10u IC4037 A1 GND JS4027 0 IC4037 AH13 DQ17 IC4037 AH6 A9 IC4037 P19 GND IC4037 L4 TEST IC4037 F3 UVIB4 IC4037 AK8 BA1 IC4037 AH8 A2 IC4037 AG7 VDD25 DDR2.5V IC4037 E9 GND IC4037 U1 GYIA0 IC4037 P2 RVIA4 IC4037 E28 UVIC5 IC4037 AK24 GND 0.1u 10V C4412 IC4037 N3 RVIA0 IC4037 W13 VDD25 C4366 47u 6.3V IC4037 B13 FHQCIN9 IC4037 AJ3 NSDCLO IC4037 E17 GND IC4037 AK14 DQS0 IC4037 W18 VDD12 IC4037 B8 THQYO2 0.1u 10V C4372 IC4037 W19 VDD12 IC4037 B6 THQCO0 1000p 50V C4402 IC4037 AF8 GND IC4037 C14 FHQCIN5 IC4037 W3 HSIA IC4037 C5 THQCO5 IC4037 Y5 GND IC4037 AF3 DQ12 IC4037 AK18 GND R4038 EXB2HV103JV IC4037 G4 UVIB7 0.1u 10V C4395 IC4037 AG2 DQ10 C4379 10V 0.1u IC4037 F28 VSIC IC4037 A16 FHQCIN1 IC4037 AJ10 DQ23 IC4037 M2 CLKIA IC4037 AG24 GND IC4037 C23 OSDVSI IC4037 E13 GND 0.1u 10V C4411 IC4037 B30 YIC1 R4022 1k IC4037 AG1 DQ14 IC4037 AH14 DQ7 IC4037 AE3 DQ15 IC4037 U17 VDD12 IC4037 W14 GND IC4037 AK1 GND IC4037 N14 VDD12 IC4037 E2 CLKIB1 IC4037 AJ2 GND IC4037 G27 GND IC4037 A8 THQYO1 1000p 50V C4394 IC4037 AH27 GND R4715 0 IC4037 AF2 DQ13 IC4037 AH28 VDD12 IC4037 A27 YIC7 IC4037 Y26 GND 0.1u 10V C4401 IC4037 AH24 GND IC4037 H3 YIB2 IC4037 A19 OSDI11 IC4037 AK7 A1 IC4037 AD27 CLKID2 R4719 68 IC4037 R18 GND IC4037 G3 UVIB8 R4714 EXB2HV221JV IC4037 AE1 DQS3 1000p 50V C4371 IC4037 W17 GND IC4037 A15 FHQCIN4 IC4037 AK15 DQ5 IC4037 C20 OSDI6 IC4037 G2 UVIB9 IC4037 B14 FHQCIN6 IC4037 P1 BUIA2 IC4037 AJ14 DQ6 IC4037 AH9 BA0 IC4037 A9 FHQCKIN IC4037 D27 GND C4388 10V 1u IC4037 B10 FHQYIN8 1u 10V C4410 IC4037 W2 VSIA R4708 68 IC4037 AC26 GND IC4037 C6 THQCO1 IC4037 AH5 A7 IC4037 C25 MOSDVSO IC4037 C19 OSDI9 IC4037 T13 GND IC4037 AJ13 DQ16 IC4037 AD26 GND IC4037 AF20 GND IC4037 U14 GND IC4037 H27 GND IC4037 H26 GND IC4037 U12 GND IC4037 AD1 DQ25 IC4037 AJ15 DQ4 IC4037 D14 GND 1000p 50V C4396 IC4037 G26 GND R4710 0 IC4037 C24 ALPHAI1 IC4037 AE26 VDD12 IC4037 AJ24 GND IC4037 AB2 VDD25 IC4037 AF26 VDD12 IC4037 M17 GND C4027 1u 10V IC4037 L27 GND IC4037 AK2 GND IC4037 A23 CLKID C4360 10V 1u IC4037 R3 BUIA3 IC4037 AK5 A6 IC4037 B28 YIC3 IC4037 D21 GND IC4037 AJ16 DQ2 IC4037 AF13 GND IC4037 M5 GND R4712 0 C4015 6.3V 10u IC4037 V19 VDD12 JS4069 220 IC4037 AH3 GND R4706 0 IC4037 H4 YIB1 IC4037 E25 GND IC4037 M27 GND IC4037 AG5 AVDD_DDR IC4037 B2 GND IC4037 AG26 GND IC4037 A12 FHQYIN3 IC4037 P12 VDD12 IC4037 A11 FHQYIN6 IC4037 AA5 GND IC4037 D9 THQYO0 IC4037 AH10 CAS IC4037 B22 OSDI1 IC4037 AG9 GND IC4037 M13 VDD12 1u 10V C4405 1000p 50V C4409 IC4037 D23 TRST IC4037 N12 VDD12 IC4037 C26 TMS IC4037 C29 YIC0 IC4037 H5 GND 0.1u 10V C4374 IC4037 A29 YIC2 C4365 10V 1u IC4037 T26 GND IC4037 C2 VDD12 IC4037 R19 GND IC4037 E4 VDD12 IC4037 P14 VDD12 IC4037 U3 RVIA6 IC4037 D4 GND IC4037 B26 MOSDHSO IC4037 AG14 AVDD_DDR 0.1u 10V C4382 IC4037 V13 VDD25 IC4037 U13 GND IC4037 E29 UVIC6 IC4037 N15 GND R4720 68 IC4037 R17 GND IC4037 M1 CLKOA C0CBCAC00282 IC4029 1 VDD 2 GND 3 CE 5 VOUT 4 NC C4363 10V 0.1u IC4037 M15 GND 0.1u 10V C4117 1000p 50V C4375 0.1u 10V C4392 IC4037 AB4 VDD25 IC4037 AJ17 GND IC4037 AA4 GND 0.1u 10V C4381 IC4037 B25 ENBID IC4037 U18 VDD12 IC4037 AF1 DQS1 0.1u 10V C4386 IC4037 P3 RVIA3 IC4037 E5 GND IC4037 AJ7 A10 IC4037 L2 BUIA0 IC4037 AD2 DQ27 IC4037 AH23 GND IC4037 AH2 DQ9 L4054 J0JHC0000078 IC4037 AG10 VDD25 IC4037 AA1 VDD25 IC4037 AG13 GND IC4037 C27 YIC5 IC4037 AK12 GND IC4037 T27 GND IC4037 E6 GND IC4037 A25 ALPHAI0 IC4037 U19 VDD12 IC4037 B16 FHQCIN0 IC4037 M3 FRCKO1 IC4037 C11 FHQYIN4 IC4037 B3 THQVOUT IC4037 N13 VDD12 IC4037 AF27 VDD12 IC4037 M16 GND 1000p 50V C4387 IC4037 A10 FHQYIN9 IC4037 T18 VDD12 IC4037 F5 VDD12 IC4037 AH17 GND IC4037 AB5 VDD25 IC4037 M14 VDD12 R4718 68 1000p 50V C4376 MAIN3.3V IC4037 T14 GND IC4037 M26 GND IC4037 W12 VDD25 IC4037 V14 GND IC4037 B18 OSDI13 IC4037 AK16 DQ1 IC4037 C21 OSDI3 IC4037 E26 GND IC4037 T17 VDD12 IC4037 B5 THQCO4 IC4037 AF5 AVSS_DDR IC4037 AH11 DQ20 IC4037 Y1 GYIA7 1000p 50V C4380 IC4037 AA3 GND IC4037 B29 GND R4701 68 IC4037 AK6 A11 IC4037 F4 UVIB3 IC4037 L26 GND IC4037 AC4 AVDD_DDR IC4037 C4 THQCO9 IC4037 AH18 GND R4287 0 MAIN1.2V PORT-C(PEAKS) PORT-D(OSD INPUT) PORT-A(ADV7499) PORT-B(FS&HDMI) PORT-FHQ(GC3E&HQ1) 27MHz 27MHz 50 53 47 51 48 49 54 46 52 IC4037 MN84522-A GC5 PROCESSOR DLL 2.5V 111 114 115 116 117 96 95 97 94 93 92 91 112 113 DG-BOARD (6/8) TNPA3756DJ TH-42PV65C DG-Board (6 of 8) Schematic Diagram TH-42PV65C DG-Board (6 of 8) Schematic Diagram 93 14.32.DG 电路板 （7/8）线路图 Thermal Pad + + + Thermal Pad A_ROE0 B_DDR_DQ10 B_DDR_DQ12 A_VSOE B_DDR_A2 A_ROE1 B_DDR_DQ29 B_DDR_A10 B_DDR_DQ19 B_DDR_NCLK B_DDR_DQS2 B_DDR_CLK A_DDR_DQ4 B_DDR_A7 A_DDR_DQ8 B_DDR_CAS B_DDR_CLK A_DDR_DQ3 A_DDR_DQ9 A_DDR_DQ29 B_DDR_DQ26 A_DDR_NCLK B_DDR_DQ3 B_DDR_DQS3 B_DDR_NCLK A_DDR_SDCKE B_DDR_DQ4 A_ROE8 B_DDR_DQ16 A_DDR_CLK B_DDR_BA0 A_DDR_CAS B_DDR_DQ0 B_DDR_DQ30 B_DDR_DQ11 B_DDR_DQ27 A_ROE7 A_DDR_A10 B_DDR_A1 B_DDR_A0 A_DDR_DQ17 A_DDR_DQ14 A_ROE5 A_GOE8 B_DDR_DQ21 B_DDR_CAS B_DDR_A2 B_DDR_DQS3 B_DDR_DQ28 B_DDR_DQ1 B_DDR_DQ25 A_ROE6 A_GOE7 A_DDR_DQ28 B_DDR_DQ15 B_DDR_DQ4 A_DDR_A1 A_DDR_DQ2 A_ROE2 A_GOE5 B_DDR_DQ21 A_DDR_DQ21 B_DDR_WE A_ROE3 A_GOE6 B_DDR_A9 B_DDR_DQ5 B_DDR_WE B_DDR_DQ18 A_ROE4 B_DDR_DQ13 A_GOE2 B_DDR_DQ8 B_DDR_A5 B_DDR_DQ0 B_DDR_RAS A_DDR_DQS0 B_DDR_A7 A_ROE9 A_GOE3 B_DDR_DQ3 A_DDR_DQ25 A_DDR_DQ10 B_DDR_DQ22 B_DDR_A11 B_DDR_DQ22 A_DDR_DQ30 A_GOE4 A_DDR_A7 A_DDR_DQ6 B_DDR_SDCKE B_DDR_DQ27 A_DDR_A2 A_DDR_DQ12 A_GOE9 GC_RST B_DDR_DQS1 B_DDR_A4 B_DDR_DQS0 B_DDR_BA1 B_DDR_A6 B_DDR_DQ29 A_DDR_A0 B_DDR_DQ6 A_DDR_DQ16 B_DDR_DQ9 B_DDR_DQ28 B_DDR_DQ16 B_DDR_A8 B_DDR_DQ12 B_DDR_RAS A_GOE0 B_DDR_DQ9 B_DDR_DQ14 B_DDR_DQ8 B_DDR_DQ25 A_DDR_DQ13 A_DDR_DQS3 A_GOE1 B_DDR_DQ2 B_DDR_DQ18 A_DDR_BA1 B_DDR_DQ6 B_DDR_DQ13 B_DDR_DQ10 B_DDR_A5 A_DDR_BA0 A_BOE0 A_DDR_WE A_DDR_A8 A_DDR_DQ11 B_DDR_A4 B_DDR_DQ14 B_DDR_DQS2 A_DDR_DQ22 A_BOE1 B_DDR_DQ24 B_DDR_DQ31 B_DDR_A10 A_DDR_DQ19 B_DDR_DQ2 A_DDR_DQS1 B_DDR_BA1 A_BOE2 B_DDR_DQ23 A_DDR_DQ27 A_DDR_A11 A_DDR_DQ24 B_DDR_A1 A_DDR_DQ31 A_BOE7 A_DDR_DQ15 B_DDR_DQ30 B_DDR_DQ17 A_BOE3 A_DDR_DQ5 A_DDR_A5 A_DDR_DQ0 A_DDR_RAS A_BOE8 B_DDR_A11 B_DDR_DQ20 A_BOE4 A_DDR_A9 A_DDR_DQS2 B_DDR_DQ17 A_BOE9 A_DDR_DQ20 B_DDR_A3 B_DDR_DQ23 A_DDR_A4 A_DDR_DQ23 A_BOE5 B_DDR_A8 B_DDR_A0 B_DDR_DQ20 B_DDR_DQ5 A_DDR_A3 A_BOE6 B_DDR_DQS0 B_DDR_DQ24 A_DDR_DQ18 B_DDR_DQ19 B_DDR_DQ7 A_DDR_A6 A_DDR_DQ7 B_DDR_DQ11 A_OSDMSK B_DDR_BA0 A_DDR_DQ26 B_DDR_DQ26 B_DDR_A9 A_DDR_DQ1 B_DDR_A3 B_DDR_DQ1 B_DDR_DQ7 B_DDR_SDCKE A_HSOE B_DDR_DQ31 B_DDR_DQ15 B_DDR_A6 SDA2 SCL2 B_DDR_DQS1 A_CLKOE C4513 10V 0.1u R4791 47 IC4037 AD28 GOF5 R4759 68 IC4037 T28 ROE6 L4056 J0JCC0000077 R4788 EXB2HV470JV IC4037 R5 VDDW IC4038 D11 VDDQ IC4037 U30 ROE5 C4482 50V 18p C4428 10V 0.1u IC4038 A9 DQ28 R4732 4.75k IC4037 V5 VDDW IC4038 G12 DQS1 1000p 50V C4437 IC4038 F6 VSS_Thermal JS4035 0 IC4038 B1 DQ4 IC4038 L5 A2 R4265 32.4k IC4038 J2 DQ23 0.1u 10V C4452 IC4038 C12 DQ25 IC4037 U27 VDDW IC4038 K6 VDD IC4037 AK27 ROF0 R4750 EXB2HV680JV IC4037 E20 VDDW IC4038 G11 DM1 TP4041 DDR_2.5V C4023 6.3V 10u R4765 0 IC4032 C0DBGYY00052 1 VOUT 2 NC 3 GND 4 NC 5 CONT 6 NC 7 NC 8 VIN IC4038 M7 A4 R4739 3.3k IC4038 J1 DQ22 IC4037 W4 OEBLK 1000p 50V C4457 IC4037 N28 GOE5 IC4038 G4 VSSQ R4775 47 IC4037 D12 NRST C4462 10V 0.1u IC4038 K10 VDD IC4037 V29 ROE1 C4508 16V 0.01u IC4038 F11 DQ13 IC4037 H29 HSOE IC4037 E24 VDDW IC4038 G8 VSS_Thermal C4498 470p 50V JS4040 IC4038 C10 VSSQ IC4037 AF30 GOF1 1000p 50V C4481 R4796 EXB2HV470JV IC4038 D5 VSSQ IC4037 AH29 ROF4 C4510 10V 0.1u IC4037 K30 BOE6 IC4037 AE30 GOF4 1000p 50V C4475 IC4037 AG17 TESTIO_DDR 1u 10V C4435 IC4037 J29 BOE8 IC4037 AK21 VREF IC4038 F12 DQ12 L4060 J0JCC0000077 IC4037 AG21 GND_DAC IC4038 L3 NC IC4038 L1 RAS IC4037 J26 VDDW IC4038 J10 VDDQ IC4038 B9 VDDQ IC4038 M10 A8/AP IC4037 AK19 IOUT R4777 47 JS4036 0 IC4037 L28 BOE1 1000p 50V C4451 C4523 16V 0.01u IC4038 H10 VDDQ IC4037 K26 VDDW MAIN1.2V IC4037 L5 VDDW IC4038 E6 VSS_Thermal IC4037 AD30 GOF7 1000p 50V C4480 IC4038 M12 VREF IC4037 AA28 BOF4 IC4037 M29 GOE9 IC4037 H30 CLKOE R4779 47 IC4038 F3 VDDQ IC4038 K2 WE IC4038 C5 VSSQ IC4037 D19 VDDW R4794 22 1000p 50V C4439 IC4037 AA29 BOF5 IC4038 A5 DQ2 IC4037 E19 VDDW IC4037 AK28 ROF2 C4512 16V 0.01u IC4037 Y29 BOF8 IC4037 AA27 SSOUT IC4038 E2 DQ16 0.1u 10V C4440 C4493 10V 0.1u IC4038 D8 VSSQ C4448 16V 0.01u R4808 0 X4004 H0J270500087 C4496 10V 0.1u R4340 0 IC4038 B12 DQ27 IC4037 V26 VDDW R4804 100 C4420 10V 0.1u IC4038 A3 VSSQ IC4038 K12 NC IC4038 M2 NC IC4037 AK26 VDDW IC4038 D3 VDD R4762 EXB2HV680JV IC4038 B2 VDDQ C4470 10V 1u IC4037 AF17 GND_PLL1 IC4037 Y4 OEMUTE IC4037 AG28 ROF6 IC4038 B8 DQ30 IC4038 L4 BA1 R4746 68 IC4037 AF29 GOF0 IC4037 E8 VDDW C4421 10V 0.1u R4738 3.3k R4733 75 R4729 100 IC4037 N19 VDDW IC4038 H3 VDDQ R4807 0 IC4037 T30 ROE8 C4505 10V 0.1u IC4037 U26 VDDW JS4033 0 IC4038 G5 VSS_Thermal IC4038 C11 DQ26 IC4037 AC27 PWMK C4466 0.01u 16V IC4037 U28 ROE3 C4518 10V 0.1u IC4037 E7 VDDW 1u 10V C4478 IC4037 J30 BOE9 R4792 47 IC4038 J7 VSS IC4038 J9 VSSQ IC4037 R4 VDDW IC4037 H28 VSOE C4509 10V 0.1u IC4038 C9 VSSQ R4793 22 IC4038 C1 DQ6 IC4037 AH22 CPOUT2 IC4038 K11 NC IC4037 J28 BOE7 IC4037 F27 VDDW IC4038 B6 VDDQ IC4038 A6 DQ0 IC4038 L6 A11 R4743 68 IC4038 H12 DQ10 IC4037 V30 ROE2 IC4038 D6 VSS IC4037 L29 BOE2 C4112 6.3V 10u C4497 4V 100u IC4037 AA26 VDDW IC4037 W5 VDDW R4021 0 R4257 33k IC4038 D7 VSS IC4038 E11 DQ15 IC4037 M19 VDDW IC4037 N18 VDDW R4756 68 R4752 22 IC4037 Y30 BOF9 0.1u 10V C4477 1000p 50V C4429 IC4038 A7 DQ31 C4522 10V0.1u R4730 100 IC4037 AE28 GOF2 IC4038 B3 NC R4760 68 IC4038 A2 DM0 IC4037 V27 VDDW C4516 10V 0.1u R4764 0 1000p 50V C4438 IC4037 V16 GNDPLLDDR IC4037 M18 VDDW C4418 1u 10V C4006 6.3V 10u IC4037 AJ27 ROF1 IC4037 J27 VDDW IC4038 G6 VSS_Thermal C4504 16V 0.01u IC4037 K27 VDDW C4521 16V 0.01u IC4037 L30 BOE3 R4806 1k C4526 10V 0.1u IC4037 AH30 ROF5 IC4038 L8 A5 1000p 50V C4454 R4269 0 IC4037 AJ23 XTALOUT IC4037 N26 VDDW MAIN1.8V JS4034 0 IC4038 K3 VDD IC4037 N27 VDDW IC4037 Y28 BOF7 IC4037 R29 GOE0 IC4037 AC30 BOF0 IC4037 W29 HSOF R4805 1k IC4038 J8 VSS 1000p 50V C4442 IC4038 J3 VDDQ C4503 10V 0.1u IC4038 D12 DQ24 IC4037 P26 VDDW IC4038 J12 DQ8 C4511 10V 0.1u IC4038 G9 VSSQ IC4037 D13 LCDMODE IC4038 G3 NC IC4037 P4 VDDW IC4038 F7 VSS_Thermal IC4038 G10 NC IC4037 W30 CLKOF R4341 0 1000p 50V C4460 L4057 J0JCC0000077 IC4037 W15 VDDPLLDDR 0.1u 10V C4456 R4776 EXB2HV470JV JS4039 IC4038 A12 DQS3 L4061 J0JCC0000077 C4506 16V 0.01u IC4038 F9 VSSQ IC4037 K29 BOE5 IC4037 D15 VDDW IC4037 AE29 GOF3 IC4038 M4 A0 R4810 0 C0CBCBC00190 IC4030 1 VDD 2 GND 3 CE 5 VOUT 4 NC IC4038 J5 VSS IC4037 AB26 VDDW R4778 EXB2HV470JV IC4038 F1 DQ19 L4055 J0JHC0000078 IC4038 H7 VSS_Thermal IC4037 AK22 DDREFIN IC4037 N30 GOE7 IC4037 AK20 COMP IC4038 D1 DQ7 IC4038 D2 VDDQ IC4038 E3 VDDQ IC4038 E7 VSS_Thermal IC4037 AB27 PTVEN IC4038 M8 A6 IC4038 K7 VDD C4464 1u 10V C4447 1u 10V C4499 56u 4V IC4038 E8 VSS_Thermal IC4038 A4 DQ3 IC4038 L9 RFU2 R4734 22k IC4037 AH19 VCOINV2 1000p 50V C4476 IC4038 C8 VSSQ C4461 82p 50V IC4037 AG18 GND_PLL1 IC4037 AJ22 DDREFOUT IC4038 L11 CK R4745 68 IC4038 G1 DQS2 R4338 0 C4514 16V 0.01u R4773 47 R4774 EXB2HV470JV IC4038 J6 VSS 1000p 50V C4422 IC4038 E1 DQ17 IC4037 AD29 GOF6 IC4038 B7 VDDQ IC4038 F2 DQ18 IC4038 H11 DQ11 IC4037 E11 VDDW IC4038 M1 CS R4046 0 IC4038 M3 BA0 0.1u 10V C4459 IC4037 R28 ROE9 R4809 0 R4754 22 1000p 50V C4453 R4757 68 IC4037 AG29 ROF7 R4772 EXB2HV470JV IC4037 W16 GNDPLLDDR IC4038 F4 VSSQ IC4037 AK25 VCOIN R4758 68 IC4037 M30 BOE0 IC4038 A8 DQ29 IC4038 K5 A10 C4465 0.1u 10V L4066 J0JHC0000078 IC4038 B5 DQ1 C4527 16V 0.01u IC4037 AJ19 TESTIO_PLL2 IC4038 E9 VSSQ R4339 0 R4811 0 IC4038 E12 DQ14 C4474 10V 1u C4007 6.3V 10u MAIN5V IC4038 C4 VSSQ IC4038 K4 VSS IC4038 G7 VSS_Thermal IC4037 AA30 BOF6 IC4038 L12 MCL IC4037 D11 VDDW R4737 0 IC4038 F5 VSS_Thermal MAIN3.3V MAIN3.3V C4008 6.3V 10u IC4037 F26 VDDW IC4038 L7 A9 C4417 47u 6.3V IC4037 AF18 VDD_PLL1 0.1u 10V C4426 IC4037 AG19 GND_PLL2 IC4037 AG30 ROF8 IC4038 M6 A3 IC4037 E15 VDDW IC4038 E10 VDDQ IC4038 C7 VDD IC4037 P29 GOE3 1000p 50V C4430 IC4038 M5 A1 IC4038 D10 VDD IC4038 F8 VSS_Thermal IC4037 N29 GOE6 R4751 22 C4507 10V 0.1u IC4037 AC29 GOF9 IC4035 C0CBCAF00031 1 VOUT 2 NC 3 GND 4 CN 5 CONT 6 NC 7 NC 8 VIN IC4038 G2 DM2 IC4038 M9 A7 IC4038 D4 VSS IC4037 AB29 BOF2 L4077 J0JCC0000077 1000p 50V C4427 IC4037 T29 ROE7 R4293 0 IC4038 H8 VSS_Thermal IC4037 AF22 DAC_VDD IC4037 P28 GOE2 IC4038 H4 VSSQ 1000p 50V C4423 IC4038 C6 VDD IC4037 AJ25 EXCLKIN IC4037 P27 VDDW IC4038 B10 NC C4005 6.3V 10u IC4037 M28 GOE8 C4519 16V 0.01u C4415 10V 0.1u IC4037 AH25 FRCLKIN IC4037 V4 SCL_MC IC4038 H9 VSSQ IC4038 H6 VSS_Thermal IC4037 U4 SDA_MC TP4037 IC4038 E4 VSSQ IC4038 A1 DQS0 1000p 50V C4434 IC4037 AJ30 ROF3 IC4037 E23 VDDW C4525 16V 0.01u C4467 0.1u 10V 1000p 50V C4458 IC4038 A11 DM3 IC4037 AF28 ROF9 IC4038 H1 DQ21 IC4037 E16 VDDW IC4037 AB30 BOF3 C4501 10V 0.1u IC4037 AC28 GOF8 C4494 10V 1u IC4037 AJ18 TESTIO_PLL1 IC4037 P30 GOE4 IC4038 E5 VSS_Thermal R4342 0 IC4038 B11 VDDQ IC4037 R30 GOE1 IC4038 D9 VSS IC4038 F10 VDDQ IC4037 K28 BOE4 1000p 50V C4479 R4735 2k IC4037 K5 VDDW IC4038 M11 CKE IC4037 AF19 VDD_PLL2 1000p 50V C4441 IC4037 E12 VDDW C4419 1u 10V R4744 68 R4033 10k IC4038 B4 VDDQ IC4037 P5 VDDW IC4037 D20 VDDW JS4038 1u 10V C4455 IC4037 AG20 GND_PLL2 C4517 16V 0.01u IC4037 AB28 BOF1 C4524 10V 0.1u IC4038 K1 CAS 1000p 50V C4424 IC4038 K9 VSS IC4038 C2 DQ5 C4502 16V 0.01u R4731 1k IC4038 K8 RFU1 IC4038 A10 VSSQ R4749 EXB2HV680JV IC4038 L2 NC IC4038 J4 VSSQ R4763 0 IC4037 W28 VSOF IC4038 H5 VSS_Thermal R4753 22 C4520 10V 0.1u IC4037 G29 SCL IC4037 U29 ROE4 IC4038 J11 DQ9 IC4038 H2 DQ20 JS4037 IC4037 G30 SDA IC4037 V28 ROE0 0.1u 10V C4425 IC4037 AJ21 IREF C4483 50V 15p C4028 16V 0.01u 1000p 50V C4436 IC4037 AF21 GND_DAC IC4037 AK23 XTALIN R4747 68 C4515 10V 0.1u IC4038 C3 VSSQ IC4038 L10 CK L4065 J0JHC0000078 R4782 22 MAIN3.3V R4785 4.7k R4783 4.7k R4784 22 MAIN3.3V PLL3.3V Must Connect Low 0.49-0.51VDDQ (PWMC) (PWMD) (PWMB) (LVDS-EN) (LCDSS) (PWMA) PORT-E PORT-F(out) (output for FHD&PWM) (output for Panel) 58 59 61 55 60 62 56 63 57 GC5 PROCESSOR MN84522-A IC4037 128M DDR SDRAM IC4038 C3ABQJ000048 MAIN 1.2V DDR 2.5V PLL 3.3V 131 132 133 134 135 113 111 111 115 114 117 116 112 DG-BOARD (7/8) TNPA3756DJ TH-42PV65C DG-Board (7 of 8) Schematic Diagram TH-42PV65C DG-Board (7 of 8) Schematic Diagram 94 14.33.DG 电路板 （8/8）线路图 + + B_CLKOE LVDS_PD JTAG_TCK JTAG_TMS JTAG_TRST DTV_RST JTAG_GC5_BA A_OSDMSK A_BOE9 A_BOE8 A_BOE7 A_BOE6 A_BOE5 A_BOE4 A_BOE3 A_BOE2 A_BOE1 A_BOE0 A_GOE9 A_GOE8 A_GOE7 A_GOE6 A_GOE5 A_GOE4 A_GOE3 A_GOE2 A_GOE0 A_GOE1 B_BOE9 B_BOE8 B_BOE7 B_BOE6 B_BOE5 B_BOE4 B_BOE3 B_BOE2 B_BOE1 B_BOE0 B_GOE9 B_GOE8 B_GOE7 B_GOE6 B_GOE5 B_GOE4 B_GOE3 B_GOE2 A_CLKOE A_HSOE A_VSOE A_ROE0 A_ROE1 A_ROE2 A_ROE3 A_ROE4 A_ROE5 A_ROE6 A_ROE7 A_ROE8 A_ROE9 B_ROE9 B_ROE8 B_ROE7 B_ROE6 B_ROE5 B_ROE4 B_ROE3 B_ROE2 B_ROE1 B_ROE0 B_VSOE B_HSOE B_CLKOE B_OSDMSK B_GOE1 B_GOE0 B_OSDMSK B_VSOE B_HSOE B_BOE9 B_BOE8 B_BOE7 B_BOE6 B_BOE5 B_BOE4 B_ROE2 B_ROE3 B_GOE2 B_GOE3 B_ROE1 B_GOE0 B_BOE1 B_ROE4 B_ROE9 B_GOE5 B_GOE7 B_GOE9 MAIN3.3V B_BOE0 B_GOE1 B_BOE3 B_GOE8 B_GOE6 B_ROE8 B_GOE4 B_ROE6 B_ROE7 B_ROE5 B_BOE2 B_ROE0 BS_Y(V) JTAG_BA_FS JTAG_TRST PEAKS-CLKIN R4969 68 JS4046 0 C4534 50V 1000p C4538 10V 0.1u R4960 EXB2HV680JV C4537 100u 4V C4530 50V 1000p R4343 0 R4962 68 R4018 10k R4968 68 R4972 68 R4963 68 R4966 68 R4824 J0JAD0000025 1 2 3 4 L4068 J0JHC0000078 C4531 50V 1000p R4964 EXB2HV680JV R4823 J0JAD0000025 1 2 3 4 L4070 J0JHC0000078 R4838 1.1k ZA4002 K4CD08000002 C4528 47u 6.3V MAIN3.3V R4971 68 C4529 10V 0.1u C4532 10V 0.1u R4819 22k C4539 1u 10V R4967 EXB2HV680JV C4540 50V 1000p R4816 22k L4069 J0JHC0000078 R4837 22 JS4103 R4814 10k R4965 68 C4533 10V 0.1u R4825 J0JAD0000025 1 2 3 4 R4822 10k R4817 22k DG35 1 2 3 4 5 6 7 R4961 68 C4536 1u 10V R4029 22 DG5 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 ZA4001 K4CD08000002 R4970 68 C4535 10V 0.1u R4891 0 IC4036 C0JBAP000020 1 TD5 2 GND 3 TD6 4 TE0 5 TE1 6 TE2 7 VCC 8 TE3 9 TE4 10 GND 11 TE5 12 CLKIN 13 /PDWN 14 PLL_GND 15 PLL_VCC 16 TE6 17 LVDS_GND 18 TE+ 19 TE- 20 TD+ 21 TD- 22 TCLK+ 23 TCLK- 24 TC+ 25 TC- 26 LVDS_GND 27 LVDS_VCC 28 TB+ 29 TB- 30 TA+ 31 TA- 32 LVDS_GND 33 TA0 34 TA1 35 TA2 36 TA3 37 TA4 38 TA5 39 GND 40 TA6 41 TB0 42 TB1 43 RS 44 TB2 45 TB3 46 TB4 47 GND 48 TB5 49 TB6 50 TC0 51 VCC 52 TC1 53 TC2 54 TC3 55 TC4 56 GND 57 TC5 58 TC6 59 TD0 60 R/F 61 TD1 62 TD2 63 TD3 64 TD4 BSD MONITOR OUT JTAG TMS TDI GND TDO TRST XRST TCK 67 68 70 64 69 71 65 72 66 LVDS TRANSMITTER(10bit) TX_TC+ TX_TD+ TX_TB+ TX_TB- TX_TCLK+ TX_TE+ TX_TC- TX_TE- TX_TD- TX_TA- TX_TA+ TX_TCLK- TO D-BOARD (D5) FOR FACTORY USE DG-BOARD (8/8) TNPA3756DJ TH-42PV65C DG-Board (8 of 8) Schematic Diagram TH-42PV65C DG-Board (8 of 8) Schematic Diagram JS4117 JS4118 CD CE CG CF CB CC CA CK CN CP CL CM CH CJ CQ CR CS CT CU CV CW CX CY DG DA DC DV DW DU DX DS DT DR DQ DK DN DE DP DL DM DD DH DJ DB DF 131 132 133 134 135 JS4117 JS4118 SUFFIX DJ 95 14.34.D 电路板 （1/2）方框图 LED_G ALARM LED_R READY PANEL_MAIN_ON REMOCON LED_R TUNER_SUB_ON TXD_PC ECO_ON TUNER_SUB_ON REMOCON ECO_ON IIC_CONT SOS4_PS RXD_PC TXD_PC VDATA_DET IIC_INT LED_G RXD_PC ALL_OFF AC_GOOD ALL_OFF AC_GOOD LED_G LED_R READY ALARM PANEL_MAIN_ON SOS8_SS SOS6_SC1 STB_SCL01 SOS7_SC2 STB_SDA01 IIC_INT IIC_CONT RXD_PC STB_SDA02 REMOCON TXD_PC VDATA_DET SOS4-PS STB_SCL02 IIC_CONT IIC_INT D9035 D9804 RA_E ,RB_E ,RC_E ,RD_E ,RE_E E+LVDS2 (RX_TC+) 6 RCLK_E E-LVDSCLK (RX_TCLK-) E+LVDS0 (RX_TA+) 10 D5 2 E-LVDS0 (RX_TA-) TO DG5 14 E+LVDSCLK (RX_TCLK+) E-LVDS2 (RX_TC-) E-LVDS1 (RX_TB-) 12 11 LVDS_DET 15 E+LVDS3 (RX_TD+) 7 5 9 16 E+LVDS4 (RX_TE+) E-LVDS3 (RX_TD-) E+LVDS1 (RX_TB+) 1 E-LVDS4 (RX_TE-) 4 LED_R PDB1 PDB0 17 14 P5V 14 29 2 LED_G 16 18 REMOCON VDATA_DET LED_G 13 D3 37 TO DG3 STBY 3.3V 15 STB5V_M 7 D25 STB 3.3V +5V 20 2 STBY3.3V REMOCON 9 ALARM LED_R DISPEN IIC_CONT IIC_INT 1 11 P3V_SCL1 P3V_SDA1 PSLCT 10 PBUSY STB3.3V SDA2 9 TXD D6 18 ALL OFF 5 STB 5V_M 33 SCL1 FOR FACTORY SCL2 10 3 STBY5V 16 12 P15V 15 21 USE 27 34 STB_SCL02 STB_SDA02 1 P15V PANEL_STBY_ON 30 17 TO P25 6 P15V STB5V_M IIC_DATA1 F_STBY_ON +15V STBY5V 15 IIC_CLK1 RXD +5V 35 21 20 P3V_SCL1 TUNER_SUB_ON 8 Q9044 6 TXD 1 7 STB_SDA02 10 STB_SCL02 SDA1 ALL OFF P3V_SDA1 23 PDB0 ECO_ON 22 READY 9 SOS4_PS 13 ECO_ON PSLCT PSTB +15V 4 16 STBY 5V 17 IIC_CLK2 IIC_DATA2 PSTB PANEL_MAIN_ON IIC/INT IIC_CONT 13 19 P15V RXD 19 8 PDB1 5 2 4 PBUSY 19 AC GOOD AC GOOD 11 TEMPERATURE VO RESET 13 12 23 73 VO 15 IC9001 FB G2 76 P15V Voltage 6 24 D2 50 10 VCC SOS7_SC2 25 EEPROM AVR P1.5V 5 LX P15V D1 P2.5V SDA VOUT VCC 51 15V 2.5V SENSOR 6 P1.5V 24 SCL 26 STB 3.3V/RESET FB 5 IC9801 Q9058 PROM(FPGA) P_ON/OFF Q9057 S2 20 DC-DC CONVERTER XRST 74 DRVMUTE 65 CTL 6 Q9051 CB NRST D2 Control DATA(D) P5V 20 SOS6_SC1 16 P3.3V D2 23 VO 21 Q9050 NCS LED_R 1 VDD 70 OUT1 REM_IN OUT1 G1 23 X9000 DRV_RST LDO_5V Q9800 1 S1 SOS3_3V D2 9.216MHz CTL 19 SOS2_15V CB DATA SDA P3V_SDA1 69 15V 3.3V ADSI IC9011 LX D2 LX P15V 24 R10-R19(R) P2.5V DATA DRIVER STB3.3V G10-G19(R) 21 OUT2 IIC1_SCL VIN 13 CONTROL IC9807 VDD G2 3 SOS9_CONF ALARM 34 DC-DC CONVERTER 9 SS PULSE VD D1 LVDS Differential 1 LVDS 18 S2 SYNC PROCESSING DRVRST WB ADJ 66 16 SCL DISCHARGE CONTROL D2 SCAN OUT 21 P1.2V 24 OUT1 P15V 1 VOUT 2 VOUT FLASH CONTROL 67 RESET SOS4-PS Q9801 FB SC PULSE P15V Q9201 VDATA_DET IC9806 5 LDO_5V Signaling 6 3 IIC2_SDA IC9800 RECEIVER 4 S2 -INC 14 Q9200 9 21 68 AVR 5V IC9500 NCS 5 22 LDO_5V VIN FPGA,ASIC ADD1 VDD CE LSI_RST VDD XRST 36 G2 1 37 DPCLK1 VDD TSET P3V_SCL1 ADD0 IC9003 6 DC-DC CONVERTER S1 STB5V 15V 1.2V 19 1 MICOM EEP_WR_CTL P3V_SDA02 18 XIN ASDIO B10-B19(R) 17 38 XOUT Q9805 TERMINAL WP Q9806 P3V_SCL02 17 G1 5 Q9046 9 D1 STB3.3V D1 D1 HD -INC -INC OUT2 DCK S1 16 PICTURE P3.3V OUTPUT 18 TXD1 17 IC9002 9 DCLK 27 RESET RXD1 5 STB_SDA02 IIC_CONT 20 STB_SCL02 DATA0 IIC_INT CTL 16 19 DCLK CB LVDS INPUT READY Q9803 VIN R 10bit 71 DIGITAL LDO_5V SOS5_5V 5 IIC1_SDA 23 Q9054 28 G 10bit IC9809 Low Q9053 20 39 SOS8_SS IC9007 B 10bit FPGA CONTROL Q9052 IIC2_SCL 13 5 LED_G VCC VDD Q9100 29 72 OUT2 G1 PANEL_MAIN_ON D1 DCK PICTURE OUTPUT R10-R19(L) G10-G19(L) R 10bit VD G 10bit B 10bit B10-B19(L) HD JTAG DISCHARGE CONTROL FLASH CONTROL XCE-L,XOE DCLK DATA0 NCS ASDIO FPGA IIC SCL SDA FPGA XRST PLL_RST 2 XRST2 DC-DC ON DIGITAL SIGNAL PROCESSOR PLASMA AI SUB-FIELD PROCESSOR FORMAT CONVERTER D LVDSCLK2 PRCKI XCE-R,XWE BYTE BUS SW NO SYNC 12 13 3 11 15 9 10 6 5 8 1 7 2 19 21 17 16 19 DISCHARGE CONTROL VD HD DCK 4 JTAG FLASH CONTROL BUS SW VD HD DCK 14 SFRST,SFVRST,LATCH FPCLK,FPDAT0,FPDAT1 TD0,TD1,TMS,TCK SS PULSE SC PULSE SS PULSE Control DATA(D) SC PULSE SOS9_C0NF DRV_RST SOS6,7,8 P+15V SOS / LED BLINKING : 2TIMES P+3.3V SOS / LED BLINKING : 3TIMES P+5V SOS / LED BLINKING : 5TIMES TH-42PV65C D-Board (1 of 2) Block Diagram TH-42PV65C D-Board (1 of 2) Block Diagram 96 14.35.D 电路板 （2/2）方框图 PCD1 CLKD0 SOS7_SC2 SOS6_SC1 CLKD1 LED CLRD SOS8_SS CLKD3 CLKD3 CLKD2 CLRD PCD2 LED CLKD1 CLKD2 CLKD0 ODED-R FREE_RUN CLKM_IN ODED_L TP9402 TP066 X9500 B 10bit st-r IC9400 CONVERTER XRST CTI/TINT WB-ADJ I/P CONVERTER COLOR FPCLK FPDAT0 FPDAT1 XRST2 SFVRST LATCH CONTRAST FORMAT SFRST Video DATA 36bit DA00-DC11 FORMAT CONVERTER/RGB PROCESSOR IC9401 DATA ROMDATA00-03 DA14,DA15-DC15 DDR SDRAM(128M) PCK OCK SUB-FIELD PLASMA AI/SUB FIELD PROCESSOR/DATA DRIVER R 10bit JTAG DCK R 10bit ROMDATA04-15 UA12-UC15 PLASMA AI G 10bit NEW DRVCLKD0-D3 HD G 10bit B 10bit VD PROCESSOR DRIVER PD1-M B 10bit st-r IC9300 CONVERTER XRST CTI/TINT WB-ADJ I/P CONVERTER COLOR FPCLK FPDAT0 FPDAT1 XRST SFVRST LATCH CONTRAST FORMAT SFRST Video DATA 36bit DA00-DC11 FORMAT CONVERTER/RGB PROCESSOR IC9301 DATA ROMDATA00-03 DA14,DA15-DC15 DDR SDRAM(128M) SUB-FIELD PLASMA AI/SUB FIELD PROCESSOR/DATA DRIVER R 10bit JTAG DCK R 10bit ROMDATA04-15 UA12-UC15 PLASMA AI G 10bit NEW DRVCLKD0-D3 HD G 10bit B 10bit VD PROCESSOR DRIVER PD1-M PCD1 TO C21 40 SCAN 2 45 5VDET L-DOWN DATA 43 SUSTAIN 37 42 1 9 DATA P5V SOS6-SC1 ODED 52 P5V Q9400 46 SOS7-SC2 1 DOUTDA0 DOUTDC7 4 58 SOS8_SS 11 TO SC20 CLKD0-L CLKD1-L 12 13 38 CLRD 20 D20 35 9 D33 P5V P5V 39 LED 47 CLKD1-R CLKD2-R CLRD CLKD3-L 31 71 72 P5V 1 69 R-DOWN D34 29 DOUTDC23 TO C11 33 CLKD2-L 30 77 P5V 45 ODED-R LED 4 23 CLKD3-R 80 36bit DA00-DC11 CLKD0-R 50 48 28 Q9402 PCD2 5VDET 12bit DA08-DC11 DOUTDA8 25 26 24bit DA00-DC07 Q9401 IC9505 LEVEL CONVERTER 3.3V 5V IC9503 LEVEL CONVERTER 3.3V 5V IC9802,03 3.3V 5V LEVEL CONVERTER CLOCK GENE. CLK7 12 CLK5 CLK6 14 13 4 CLK9 XT 1 20 XTN IC9200 IC9304 16M FLASH MEMORY RESET 4 5 VOUT VCC IC9602 RESET P3.3V DQ4-DQ15 A0-A19 DQ0-DQ3 IC9402 BUS SWITCH BUS SW ODED-R,ODED-L,PCD1,PCD2,LED,CLRD UMH,UML,USH,USL,UEH,NUEL,URH,URL CL,CLK,SIU,SID,SCSU,CEL2,CPH,CEL,CBK,CSL,CSH,CML,CMH Sustain Control DATA 8bit Scan Control DATA 13bit PCK OCK XCE-R XCE-L BYTE XWE XOE R10-R19,G10-G19,B10-B19 UA05-UC12,UC13,UA15 DA14,DA15-DC15 UA12-UC12,UC13,UA15 UA05-UC11 DA14,DA15-DC15 UA12-UC15 UA05-UC10,UB11,UC11 XCE-L 20MHz 84MHz 36.6MHz 60MHz VD HD DCK DISCHARGE CONTROL BUS SW JTAG FLASH CONTROL VD HD DCK 3 11 15 9 10 6 5 8 1 7 2 19 21 17 16 18 4 12 13 14 Control DATA(D) SS PULSE SC PULSE TD0,TD1,TMS,TCK SOS9_C0NF DRV_RST SOS6,7,8 SUB-FIELD PROCESSOR FORMAT CONVERTER D DIGITAL SIGNAL PROCESSOR PLASMA AI TH-42PV65C D-Board (2 of 2) Block Diagram TH-42PV65C D-Board (2 of 2) Block Diagram 97 14.36.D 电路板 （1/8）线路图 G G + G G 18 16 14 12 10 8 6 4 2 20 21 19 17 15 13 11 9 7 5 3 1 G G G G G G + + G G G G STB_SCL02_D4 FP_SCSU ECO_ON SC_CEL PANEL_STBY_ON FAN_SOS NCS FP_CEL INEXCH DATA0 RXD_PC FP_CBK ALARM FP_CSL SC_SID STBY3.3V TUNER_SUB_ON TUNER_SUB_ON TXD_PC READY SC_CSH SC_CPH STB_SDA02 DISPEN_D2 SC_CMH AR_IIC_INT SC_CEL STB_SCL02 PANASONIC_MODE AR_IIC_CONT PDB1_2 SC_SID RXD_PC_D4 FAN_SOS PSLCT_2 FP_CML PANEL_STBY_ON_D2 FAN_CONT PDB0_2 SC_SCSU SC_CSL FP_CL ALL_OFF FAN_CONT ASDIO PBUSY_2 DCLK SC_CLK P3V_SCL1 P3V_SCL1 PSTB_2 SC_SCSU PANEL_MAIN_ON SC_CMH SOS6_SC1 SC_CEL2 FP_CLK STB_SDA02_D4 SOS7_SC2 SC_CML P3V_SDA1 P3V_SDA1 SC_CSL SOS4_PS FP_CMH SC_CL STBY3.3V_ON FP_SIU SC_CL INEXCH_D2 P_ON/OFF SC_CSH FP_CSH AR_IIC_INT_D2 ECO_ON FP_CEL2 SC_CPH FP_SID ALARM_D2 SC_CLK TXD_PC_D4 SC_CML SC_CEL2 STBY5V_D2 READY_D2 SC_CBK SC_CBK FP_CPH ALL_OFF ALL_OFF SC_SIU SC_SIU DCDC_ON AC_GOOD DRVMUTE AC_GOOD TUNER_SUB_ON DCDC_ON REMOCON LED_R LED_G P3V_SCL1 AR_IIC_CONT_D4 PSTB PSLCT PSLCT_2 LED_R AR_IIC_INT_D2 STB_SCL02_D4 PDB0_2 STB_SDA02_D4 TXD_PC_D4 PDB0 PBUSY_2 RXD_PC_D4 PBUSY PSTB_2 P3V_SDA1 LED_G REM_IN REMOCON VDATA_DET C_SEL AR_IIC_CONT_D4 AR_IIC_CONT_D4 SOS9_CONF PDB1 PDB1_2 R9868 100k P5V Q9100 B1ABCF000138 R9896 0 P1.2V J0HABH000013 FL9800 STB5V_M R9839 100 C9898 10p 50V STB3.3V R9849 EXB2HV470JV D9808 MA3X152K0L C9845 16V 0.1u R9801 24k R9826 100 P5V P5V C9807 10u 25V C9802 47p 50V Q9801 B1MBEDA00015 S1 G1 S2 G2 D2 D2 D1 D1 D3 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 R9897 100k C9971 0.1u 16V R9893 36k D9812 B0JCME000037 P5V C9822 6.3V 10u C9926 0.1u 16V R9870 10k R9815 22k P15V R9830 10k P15V C9816 68u 4V C9882 0.1u 16V STB5V_M C9897 8200p 50V LDO_5V R9803 0 P15V_MOTO R9859 EXB38V101JV R9879 20k C9967 4.7u 6.3V D9815 B0JCDD000002 C0DBAYY00054 IC9809 1 GND 2 REFIN 3 VREF 4 CS 5 VCC 6 COVP 7 CUVP 8 PGOOD 9 CTL 10 LSAT 11 ILIM 12 +INC 13 -INC 14 N.C. 15 PGND 16 OUT-2 17 VDD 18 LX 19 OUT-1 20 CB 21 VIN 22 RT 23 VO 24 FB C9825 50V 100p C9837 10u 16V C9843 16V 0.1u Q9800 B1MBEDA00015 S1 G1 S2 G2 D2 D2 D1 D1 STB3.3V FL9803 J0HABH000012 1 2 3 D6 R9869 10k C9830 10u 16V C9847 0.1u 25V C9886 0.1u 16V C9800 0.1u 16V P3.3V LDO_5V R9884 100k R9802 62k R9823 100 Q9806 B1ABCF000138 P15V D9802 MA2J72800L R9850 47k C9846 16V 0.1u C9899 1000p 50V R9806 39k C9805 4.7u 6.3V D9801 B0JCDD000002 LDO_5V FL9807 J0HABH000013 1 2 3 R9808 100k C9841 16V 1u C9824 10u 25V C9883 8200p 50V R9878 39k D25 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 D9800 B0JCME000037 P15V L9800 G1C3R0MA0248 R9202 4.7k Q9805 B1ABCF000138 R9800 13k R9827 100 C9826 16V 0.1u C9880 50V 1000p R9847 EXB2HV272JV R9848 EXB2HV470JV R9892 15k R9843 100 C9823 10u 25V R9880 36k P15V P2.5V IC9007 1 NCS 2 DATA 3 VCC 4 GND 5 ASDI 6 DCLK 7 VCC 8 VCC P15V_MOTO R9831 10k D9813 B0JCDD000002 C9831 10u 16V J0HABH000013 FL9806 C9801 4900p 25V R9099 100 D9804 MA3X152K0L P2.5V FL9801 J0HABH000013 1 2 3 C0DBAYY00054 IC9807 1 GND 2 REFIN 3 VREF 4 CS 5 VCC 6 COVP 7 CUVP 8 PGOOD 9 CTL 10 LSAT 11 ILIM 12 +INC 13 -INC 14 N.C. 15 PGND 16 OUT-2 17 VDD 18 LX 19 OUT-1 20 CB 21 VIN 22 RT 23 VO 24 FB L9801 G1C2R2MA0241 R9824 100 C9891 0.1u 16V C9815 68u 4V C9838 16V 0.1u IC9801 C0DBZFG00066 1 VOUT 2 GND 3 CE 4 NC 5 GND 6 VDD P15V D9035 MA2J72800L R9872 0 C9806 68u 4V R9807 0 C0DBAHD00011 IC9806 1 VOUT 2 GND 3 CE 5 VDD 4 NC C9833 10u 25V C9817 10u 25V R9828 100 D20 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 C9844 50V 0.01u R9821 10k P3.3V STB3.3V R9810 3k C9808 10u 25V R9804 24k D9814 B0JCME000037 C9827 6.3V 10u P5V_MOTO R9842 100 R9883 0 C9885 1000p 50V R9845 5.6k P3.3V C0JBAZ000856 IC9802 G1 1 2 A1 3 A2 4 A3 5 A4 6 A5 7 A6 8 A7 9 A8 10 GND 11 Y8 12 Y7 13 Y6 14 Y5 15 Y4 16 Y3 17 Y2 18 Y1 19 G2 20 Vcc PA9800 K5H4022A0023 C9803 4700p 50V J0HABH000013 FL9805 C9818 10u 25V P5V_MOTO P15V P15V R9871 10k C9881 50V 1000p R9201 4.7k C0JBAZ000856 IC9803 G1 1 2 A1 3 A2 4 A3 5 A4 6 A5 7 A6 8 A7 9 A8 10 GND 11 Y8 12 Y7 13 Y6 14 Y5 15 Y4 16 Y3 17 Y2 18 Y1 19 G2 20 Vcc C9029 6.3V 10u R9198 4.7k R9846 EXB2HV272JV C9884 10p 50V R9825 100 P5V R9854 100 L9802 G1C2R2MA0241 C9804 0.1u 16V D9807 MA3X152K0L P1.5V STB5V_M C9840 16V 0.1u R9844 100 R9816 82k STB3.3V C0DBAYY00054 IC9800 1 GND 2 REFIN 3 VREF 4 CS 5 VCC 6 COVP 7 CUVP 8 PGOOD 9 CTL 10 LSAT 11 ILIM 12 +INC 13 -INC 14 N.C. 15 PGND 16 OUT-2 17 VDD 18 LX 19 OUT-1 20 CB 21 VIN 22 RT 23 VO 24 FB C9832 10u 16V R9840 22 C9842 16V 1u R9814 68k C9896 0.1u 16V C9028 6.3V 10u R9838 100 R9891 47k FL9804 J0HABH000012 1 2 3 L9810 J0JHC0000045 R9813 2.4k C9848 0.1u 25V LDO_5V STB3.3V C9809 0.1u 16V P15V Q9803 B1MBEDA00015 S1 G1 S2 G2 D2 D2 D1 D1 R9805 30k C9887 4.7u 6.3V R9841 0 SOS7_SC2 ALARM CSH INEXCH ECO_ON DISPEN GND +5V GND CML GND FAN_CONT GND CL +5V F_STBY_ON GND GND GND GND SID GND GND GND FAN_SOS GND +15V ECO_ON FAN_SOS CEL2 +15V SOS4_PS PBUSY GND PDB0 PSTB STBY5V GND PSLCT PANASONIC_MODE GND FAN_CONT 15V->1.2V 2.5V->1.5V GND +2.5V CBK CEL CSL ALL_OFF PDB1 IIC/INT P15V P5V CLK CPH GND IIC_DATA2 SCSU IIC_CLK2 IIC_CONT IIC_CLK1 STBY3.3V CMH SIU PANEL_MAIN_ON CTL GND TXD IIC_DATA1 SOS6_SC1 ALL_OFF PANEL_STBY_ON TUNER_SUB_ON RXD STBY5V READY AC_GOOD AC_GOOD LED_G REMOCON LED_R STBY5V GND P15V STBY3.3V IIC_CONT GND SCL1 SDA1 SCL2 SDA2 TXD RXD IIC_INT LED_G PSTB LED_R PDB0 PSLCT PDB1 PBUSY REMOCON VDATA_DET P5V CTL 15V->3.3V FB=0.7V CTL 15V->2.5V 15V->5V B F 1 2 3 4 5 6 7 8 9 E C D A LEVEL CONVERTER LEVEL CONVERTER P-BOARD (P25) TO DG-BOARD TO (DG3) TO SC-BOARD (SC20) FOR USE FACTORY 15V 3.3V DC-DC CONVERTER 15V 1.2V DC-DC CONVERTER DC-DC CONVERTER 15V 2.5V AVR 5V 1 2 3 TVRN814-1 PROM(FPGA) AVR 1.5V D-BOARD TNPA3820AJ(1/8) TH-42PV65C D-Board (1 of 8) Schematic Diagram TH-42PV65C D-Board (1 of 8) Schematic Diagram 98 14.37.D 电路板 （2/8）线路图 RCLK_E- SOS7_SC2 EEP_WR_CTL M_SEL1 LVDSBIT P3V_SCL1 RCLK_E+ SOS9_CONF RA_0+ RA_E- P3V_SDA1 INEXCH ALARM RB_0- SOS6_SC1 RA_E+ STB_SCL01 RB_0+ SOS8_SS EEP_WR_CTL STB_SCL01 M_SEL4 RB_E- SOS4_PS STB_SDA01 XRST XRST M_SEL3 RC_0- PANEL_MAIN_ON RB_E+ STB_SDA01 REM_IN RC_0+ C_SEL P_ON/OFF PANEL_STBY_ON SOS9_CONF RD_0- M_SEL2 LED_R NRST RC_E+ STBY3.3V_ON PANASONIC_MODE RD_0+ LED_G RD_E- RE_0- RD_E+ TXD_PC RE_0+ RE_E- RXD_PC LVDS_DET STB_SDA02 P3V_SDA02 P3V_SCL02 STB_SCL02 P3V_SCL02 XRST STB_SCL02 P3V_SDA02 STB_SDA02 RE_E+ RA_0- DRVRST XRST2 XRST2 DCLK DATA0 ASDIO NCS STB_SCL02 STB_SDA02 READY VDATA_DET LVDS_MODE M_SEL4 D5_DETO RC_E- FVSEL XRST AR_IIC_CONT AR_IIC_INT M_SEL1 M_SEL3 R9108 10k *R9157 10k R9145 100 R9172 39k R9188 5.6k R9143 100 R9148 10k R9109 10k R9121 100k R9222 10k STB5V P15V R9171 39k R9102 100 STB3.3V R9175 10k R9141 100 R9140 0 R9205 4.7k R9181 1k R9101 10k R9152 4.7k R9167 100 C9046 16V 0.1u P5V R9204 4.7k C9039 6.3V 10u R9217 10k C9033 16V 0.1u C9056 16V 0.1u R9247 4.7k R9156 10k TP9000 C9044 16V 0.1u R9190 10k C9052 16V 0.1u STB3.3V Q9200 B1CBHD000002 IC9011 C0EBF0000431 1 RESET 2 Cd 3 VOUT 4 VDD 5 GND 6 CE R9184 1k R9063 100 R9166 10k R9155 5.6k R9111 22k D9017 MAZ303300L R9203 1k R9183 1k C9051 16V 0.1u Q9057 B1CBHD000002 R9074 100 Q9046 B1ABCF000138 R9107 3.3k R9189 10k R9064 100 C9050 16V 0.1u Q9053 B1ABCF000138 R9178 10k R9100 10k R9221 10k R9207 1k R9066 100 R9120 100 *R9199 2.7k R9161 0 TVRP173-1 IC9003 1 2 3 4 5 6 CNVSS 7 8 9 RESET 10 XOUT 11 VSS 12 XIN 13 VCC 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60 61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 AVSS 76 77 VREF 78 79 80 R9150 22 *R9209 10 Q9054 B1ABCF000138 Q9058 B1CBHD000002 Q9044 B1ABCF000138 R9185 22 C9053 16V 0.1u D9020 MA2J72800L STB3.3V R9218 10k R9179 1k C9049 16V 0.1u R9067 100 R9142 100 Q9201 B1CBHD000002 C9045 16V 0.1u P3.3V R9248 4.7k R9192 0 R9180 10k R9076 100 R9164 10k R9165 10k R9129 68k R9153 4.7k STB3.3V R9095 10k Q9052 B1ABCF000138 C9037 0.01u 50V D9019 MAZ303300L R9173 10k R9144 100 P3.3V R9236 0 X9000 H2D200500011 R9113 10 Q9049 B1ADCE000011 P3.3V R9151 22 R9237 10k R9127 10k R9062 100 C9034 16V 0.1u R9174 10k C9047 16V 0.1u C9036 6.3V 10u R9159 10k R9196 10k *R9210 2.7k IC9001 1 A0 2 A1 3 A2 4 GND 5 SDA 6 SCL 7 WP 8 Vcc R9193 10k Q9051 B1ABCF000138 D5 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 R9149 4.7k IC9002 C0ZBZ0001330 1 SCL 2 GND 3 ADD1 4 V+ 5 ADD0 6 SDA P3.3V R9206 1k R9106 10k R9065 100 R9160 0 C9040 16V 0.1u R9110 100 R9219 10k C9055 16V 0.1u R9220 10k R9182 1k R9215 12k R9154 5.6k STB3.3V R9186 22 R9060 100 R9169 10k R9170 39k R9134 33k C9048 16V 0.1u R9187 5.6k R9194 0 R9061 100 STB3.3V C9057 16V 0.1u D9018 MAZ303300L C9035 6.3V 10u R9158 10k Q9050 B1ABCF000138 R9168 100 C9058 6.3V 10u STB3.3V D9101 B0JCGD000002 D9100 B0JCGD000002 D9102 B0JCGD000002 D9103 B0JCGD000002 D9106 B0JCGD000002 D9105 B0JCGD000002 D9110 B0JCGD000002 STB5V_M R9177 22k M_SEL2 R9096 10k IIC_CONT NC GND DRIVER_RESET SCLK(for Loader) IIC1_SCL SOS8_SS NC CE(Loader) E+ LVDS2 NC O+ LVDS3 E+ LVDS1 SOS4_PS GND XRST O+ LVDS0 RESET IIC1_SDA BUSY(for Loader) NC GND NC NC E- LVDS2 FPGA_CE NC SOS7_SC2 NC XOUT REM_IN SOUT(FPGA) GND NC O- LVDS3 NC FVSEL E+ LVDS3 PLL_RST M_SEL2 SIN(FPGA) NC LSI_RST E- LVDS3 M_SEL3 O+ LVDS1 ALARM INEXCH E+ LVDS4 AC_GOOD O- LVDS1 P_ON/OFF STB3.3V ON/OFF GND NC E- LVDS4 LVDS_DET E+ LVDSCLK SOS6_SC1 O+ LVDS2 NC AVCC O- LVDS2 VSS PANEL_MAIN_ON NC E- LVDS0 SOS9_CONF GND SCLK(FPGA) EEP_WR_CTL NC O+ LVDS4 LED_GRN O- LVDS4 IIC_INT E+ LVDS0 M_SEL4 NC(ALL_OFF) IIC2_SCL SOS_INH SOS5_5V XIN NC(C_SEL) IIC2_SDA PANASONIC _MODE O- LVDSCLK LVDS_MODE NC NC O+ LVDSCLK VCC E- LVDSCLK NC TXD(Loader) O- LVDS0 LVDS_BIT SOS3_3V READY RXD(Loader) INT_CONF E- LVDS1 LED_RED SOS2_15V M_SEL1 NC MAIN_CONF VDATA_DET 14 13 15 18 16 10 11 12 17 NC MICOM EEPROM SENSOR TEMPERATURE DIGITAL TO DG-BOARD (DG5) 1 3 2 12 13 14 15 16 17 11 D-BOARD TNPA3820AJ(2/8) TVRN811-2 TH-42PV65C D-Board (2 of 8) Schematic Diagram TH-42PV65C D-Board (2 of 8) Schematic Diagram STB 3.3V RESET 99 14.38.D 电路板 （3/8）线路图 L8L_RI4 L8L_GI4 FP_CL L8R_RI6 AA_BYTE A_XCE_L L8R_GI3 L8R_GI7 L8L_RI5 SOS9_CONF RD_E+ L8R_RI0 L8L_GI5 FP_CSH DD_PCD1 L8R_GI9 TDO_TO_FPGA RC_E+ L8R_GI2 RB_0- L8R_BI0 L8R_BI3 NRST RD_0+ L8L_GI6 L8R_BI8 FP_CLK L8R_BI2 FP_CSL TMS DATA0 RC_0+ SFRST FP_CBK RB_E+ L8R_GI1 FP_CEL2 L8R_GI4 L8L_RI6 L8R_GI6 NCS L8R_GI0 RE_E+ RCLK_E+ L8L_GI7 L8L_BI4 FP_SID DD_LED FP_UEH L8R_RI7 PDB0 LATCH TCK L8L_RI7 L8L_BI5 FVSEL LVDS_MODE L8L_GI8 L8L_HDI L8L_RI8 PDB1 FP_UML L8R_RI9 L8R_RI5 L8R_GI5 RA_E+ L8R_BI9 L8L_GI9 RE_0+ L8L_BI6 FPDAT1 L8L_RI9 FP_CMH PSTB RB_E- TDI_TO_68_L FP_CPH L8R_RI2 FP_UMH L8L_RI0 RD_E- L8L_BI0 L8R_RI1 L8L_BI7 FP_SCSU L8L_GI0 PBUSY RCLK_E- DD_ODED_L L8R_RI3 PSLCT L8L_RI1 L8L_BI1 L8L_BI8 RC_0- DD_CLRD AA_XWE L8L_GI1 SFVRST RA_0- FP_USH RA_E- RB_0+ LVDS_DET ASDIO RE_0- FP_NUEL DRVRST L8L_RI2 L8L_BI9 L8R_BI4 FP_CML L8L_BI2 RD_0- L8L_GI2 L8R_BI1 L8R_BI6 L8R_GI8 L8R_BI5 FP_CEL RC_E- INEXCH L8L_RI3 FP_SIU L8L_BI3 FPCLK L8R_RI8 L8R_RI4 L8L_GI3 L8R_BI7 FP_USL FPDAT0 RE_E- RA_0+ DD_PCD2 LVDSBIT L8L_VDI L8L_DCK L8L_MASK AA_XCE_R DD_ODEU_R BUS_SW L8R_HDI L8R_MASK DD_ODEU_L DD_CLRU DD_PCU1 DD_LEU DD_PCU2 P3V_SCL02 P3V_SDA02 DRVMUTE D5_DETO FP_URH FP_URL DD_ODED_R FP_DSHL FP_DSLL FP_DMHR FP_DMLL FP_DMHL L8R_VDI L8R_DCK AA_XOE DCLK IC9500 B7 LVDS21n IC9500 H3 nCONFIG IC9500 F8 GND IC9500 E13 LVDS37n R9546 10k IC9500 J5 GNDG_PLL1 IC9500 F2 LVDS8p IC9500 N8 LVDS62p IC9500 B14 LVDS33n C9520 16V 0.1u IC9500 C3 LVDS14n R9556 10k IC9500 N15 LVDS49n IC9500 L6 GND IC9500 C13 LVDS33p IC9500 G1 LVDSCLK1p IC9500 N7 LVDS64n IC9500 A5 GND IC9500 E14 LVDS38p IC9500 B8 LVDS23p R9506 22 IC9500 C7 LVDS22p IC9500 D8 LVDS24p IC9500 G12 VREF0B3 R9532 47 IC9500 R16 LVDS50p IC9500 R4 LVDS69p IC9500 H10 GND IC9500 D7 LVDS22n IC9500 B13 LVDS32n IC9500 F10 VCCIO2 IC9500 R14 LVDS53p IC9500 M9 IO R9530 10k IC9500 H14 TDI IC9500 A15 LVDS34p IC9500 B9 LVDS26p IC9500 G4 nCSO IC9500 T13 LVDS54p IC9500 P14 LVDS51p IC9500 J13 nSTATUS IC9500 C4 LVDS16n IC9500 K8 GND IC9500 R8 LVDS63p IC9500 P13 LVDS53n IC9500 T4 LVDS69n R9525 10k C9521 16V 0.1u IC9500 T5 GND IC9500 C14 LVDS35n IC9500 J3 MSEL0 C9517 16V 0.1u IC9500 A9 LVDS26n IC9500 R12 LVDS55n IC9500 K15 PLL2_OUTn R9523 10k IC9500 M11 VREF0B4 P3.3V IC9500 B3 LVDS16p IC9500 J9 GND R9552 47 IC9500 N1 LVDS4p IC9500 A12 GND IC9500 R9 LVDS61p IC9500 H8 GND C9525 16V 0.1u IC9500 D16 LVDS39p IC9500 R5 LVDS68p IC9500 H7 VCCINT IC9500 M2 LVDS4n IC9500 E11 VREF0B2 IC9500 N12 LVDS56n R9548 10k IC9500 A3 VCCIO2 IC9500 E1 LVDS8n R9875 10k C9530 16V 0.1u IC9500 A6 LVDS21p C9526 6.3V 10u IC9500 C9 LVDS25p IC9500 H11 VCCA_PLL2 IC9500 H9 VCCINT IC9500 K7 VCCINT C9522 16V 0.1u IC9500 T9 LVDS61n IC9500 G14 LVDS43n IC9500 L5 DPCLK0 IC9500 P4 LVDS70n IC9500 B6 LVDS20n IC9500 H5 VREF1B1 IC9500 P5 LVDS68n C9523 16V 0.1u IC9500 T7 VCCINT R9534 EXB38V470JV IC9500 M10 VREF1B4 IC9500 H16 LVDSCLK2n IC9500 K2 PLL1_OUTn IC9500 R7 LVDS65n R9553 47 IC9500 M13 LVDS48p C9532 50V 100p IC9500 D4 LVDS14p(INIT_DONE) IC9500 J15 TMS IC9500 F15 LVDS40n R9536 47 IC9500 F6 GND IC9500 M16 LVDS46p IC9500 A4 LVDS17n IC9500 M5 DPCLK7 IC9500 D12 LVDS30n IC9500 T16 GND IC9500 R3 LVDS70p IC9500 M7 IO IC9500 C12 LVDS31p IC9500 B11 LVDS29p IC9500 D10 LVDS27p IC9500 F11 GND P3.3V R9543 10k C9524 16V 0.1u IC9500 F9 GND R9544 10k R9244 100 IC9500 B4 LVDS17p R9877 10k IC9500 L16 LVDS44n IC9500 D6 LVDS19n IC9500 P10 LVDS58n IC9500 A11 LVDS28n IC9500 B1 LVDS13n IC9500 P2 LVDS1n IC9500 M4 LVDS2p IC9500 F4 IO IC9500 F3 LVDS9p IC9500 T1 GND P3.3V IC9500 M6 VREF2B4 IC9500 R11 LVDS57p IC9500 F1 LVDS7n IC9500 J4 nCE IC9500 D9 LVDS25n P3.3V IC9500 L2 LVDS5p IC9500 T6 LVDS65p IC9500 E16 LVDS40p IC9500 D3 LVDS12p IC9500 M8 IO R9549 10k IC9500 N6 LVDS67n IC9500 D14 LVDS37p IC9500 C15 LVDS36p IC9500 P7 LVDS64p IC9500 C6 LVDS20p IC9500 F12 DPCLK4 IC9500 K4 DCLK R9554 47 IC9500 F7 VCCIO2 IC9500 G3 LVDS9n IC9500 T11 LVDS59n IC9500 G6 VCCIO1 IC9500 L14 LVDS45n IC9500 E9 IO C9527 16V 0.1u IC9500 J16 PLL2_OUTp IC9500 A10 VCCINT IC9500 P6 LVDS66p IC9500 C5 LVDS18n IC9500 P1 VCCIO1 IC9500 D1 LVDS10n IC9500 K11 VCCIO3 IC9500 A14 VCCIO2 IC9500 N16 LVDS49p IC9500 K1 LVDS6p R9630 10k IC9500 B15 LVDS34n IC9500 A13 LVDS32p IC9500 G5 VREF0B1 IC9500 B10 LVDS28p IC9500 D13 LVDS35p IC9500 G8 VCCINT IC9500 B5 LVDS18p IC9500 L12 DPCLK5 IC9500 P9 LVDS60p IC9500 D15 LVDS38n IC9500 G13 LVDS43p IC9500 C1 VCCIO1 IC9500 P16 VCCIO3 IC9500 E10 VREF1B2 IC9500 G15 LVDS42n R9529 10k IC9500 K9 VCCINT IC9500 L8 GND R9535 47 IC9500 K14 IO IC9500 E6 VREF2B2 IC9500 L7 VCCIO4 IC9500 E15 LVDS39n IC9500 J10 VCCINT IC9500 N4 LVDS0n P3.3V IC9500 P12 LVDS55p IC9500 D2 LVDS11n IC9500 B12 LVDS31n IC9500 M14 LVDS47n IC9500 N5 LVDS67p IC9500 P8 LVDS62n IC9500 R15 LVDS52n IC9500 R1 LVDS1p IC9500 J14 TCK IC9500 A16 GND P1.5V IC9500 P3 LVDS0p R9560 10k IC9500 F13 LVDS41p C9519 16V 0.1u IC9500 H1 LVDSCLK1n IC9500 E2 LVDS10p IC9500 G9 GND R9531 47 IC9500 P15 LVDS50n IC9500 C16 VCCIO3 IC9500 J8 VCCINT IC9500 P11 LVDS57n IC9500 A2 LVDS15n IC9500 T14 VCCIO4 IC9500 C8 LVDS24n IC9500 J6 GNDA_PLL1 IC9500 F16 LVDS42p IC9500 J2 MSEL1 IC9500 E12 DPCLK3 IC9500 K12 VREF2B3 IC9500 F5 DPCLK1 IC9500 T12 GND IC9500 L13 LVDS47p IC9500 L9 GND C9528 16V 0.1u IC9500 L4 IO L9501 J0JHC0000078 IC9500 E3 LVDS11p IC9500 T3 VCCIO4 IC9500 L10 VCCIO4 IC9500 D11 LVDS30p R9876 10k IC9500 R13 LVDS54n IC9500 R6 LVDS66n IC9500 M12 DPCLK6 IC9500 C2 LVDS13p(CLKUSR) IC9500 C10 LVDS27n IC9500 J12 GNDG_PLL2 IC9500 N10 LVDS58p IC9500 K5 VREF2B1 C9516 16V 0.1u IC9500 H4 nCEO IC9500 M1 LVDS5n R9533 47 IC9500 N3 LVDS2n IC9500 B2 LVDS15p IC9500 K16 LVDS44p IC9500 L1 LVDS6n C9518 16V 0.1u IC9500 L3 IO R9550 10k R9507 56 IC9500 G11 GND IC9500 G10 VCCINT IC9500 T15 LVDS52p IC9500 K3 ASDO IC9500 A8 LVDS23n IC9500 J11 GNDA_PLL2 P3.3V IC9500 R2 LVDS71p P3.3V IC9500 D5 LVDS19p R9245 100 IC9500 N2 LVDS3p IC9500 H6 VCCA_PLL1 C9531 6.3V 10u IC9500 T8 LVDS63n IC9500 N14 LVDS48n L9502 J0JHC0000078 IC9500 H2 DATA0 IC9500 J1 PLL1_OUTp IC9500 K13 CONF_DONE IC9500 N9 LVDS60n IC9500 T2 LVDS71n IC9500 L15 LVDS45p IC9500 G16 LVDSCLK2p IC9500 N13 LVDS51n IC9500 C11 LVDS29n IC9500 J7 GND IC9500 L11 GND IC9500 R10 LVDS59p IC9500 T10 VCCINT IC9500 A1 GND R9537 10k IC9500 K6 GND IC9500 M15 LVDS46n IC9500 A7 VCCINT IC9500 E8 IO IC9500 H15 TDO C9529 16V 0.1u IC9500 N11 LVDS56p IC9500 M3 LVDS3n IC9500 H13 IO IC9500 G2 LVDS7p IC9500 G7 GND IC9500 E5 DPCLK2 IC9500 E4 LVDS12n IC9500 H12 VREF1B3 IC9500 E7 IO IC9500 K10 GND IC9500 F14 LVDS41n IC9500 B16 LVDS36n R9542 68 R9545 300k R9526 0 R9070 47 B[1]_R/rromadrs[01] VCCINT M_BOUT1 FPDATA0 UEL M_BOUT4 Nosync ODED SID M_BOUT3 M_ROUT4 USH G[9]_R/rromadrs[03] PCU SC_PULSE CEL M_BOUT9 UMH M_ROUT7 M_GOUT7 USL DRVRST RESET M_BOUT8 CMH UML MASK_L PCD2 M_VDO_L FPCLK SS_PULSE INEXCH NUEL CML p_db1 B[5]_R/rromadrs[02] CSH R[8]_R/rromadrs[15] CONTROL p_db0 OTHER M_ROUT9 B[0]_R/rromadrs[00] p_stb rrom_WE CLK B[8]_R/rromdata[02] G[7]_R/rromdata[07] NRST IIC NC M_BOUT0 DMHR SCL M_GOUT5 CL M_BOUT7 M_GOUT9 M_HDO_L TP CLK_INPUT p_slct M_GOUT1 p_busy R[2]_R/rromadrs[14] SID2 M_DCKO_L PRCKI M_GOUT0 FREE RUN CLK SDA R[9]_R/rromadrs[17] M_ROUT6 DMHL TEST M_BOUT6 R[0]_R/rromadrs[19] G[2]_R/rromadrs[09] LVDS_DET MODEL[0] CEL2 R[4]_R/rromadrs[20] rrom_CE_L SCSU M_BOUT5 CPH B[7]_R/rromdata[03] SFRST M_ROUT3 R[3]_R/rromadrs[-1] PICTURE_OUTPUT(L) G[0]_R/rromadrs[10] B[2]_R/rromdata[06] M_GOUT3 rrom_BYTE rrom_OE R[7]_R/rromadrs[18] PCU2 R[5]_R/rromadrs[12] CLRD B[3]_R/rromdata[04] LATCH DATA_DRIVER G[3]_R/rromadrs[08] FPDATA1 M_GOUT6 DMLL G[6]_R/rromadrs[05] LSI58 B[6]_R/rromdata[00] PCD R[1]_R/rromadrs[13] M_BOUT2 LVDS_INPUT M_ROUT2 CSL SIU2 B[4]_R/rromdata[05] LED G[8]_R/rromadrs[06] CLRU R[6]_R/rromadrs[16] B[9]_R/rromdata[01] FVSEL ODEU SFVRST LEU SIU LVDSmode M_GOUT2 CBK M_ROUT0 M_ROUT5 G[5]_R/rromadrs[04] M_ROUT1 M_ROUT8 CLKM_IN G[1]_R/rromadrs[07] VCCI LVDSbit DRVMUTE G[4]_R/rromadrs[11] GND M_GOUT4 M_GOUT8 rrom_CE_R MASK_R M_DCKO_R M_HDO_R M_VDO_R DSLL DSHL XRST BUS_SW PICTURE_OUTPUT(R) /FLASH_CONTROL URH URL D5_DETO WHITE SIGNAL ODEU ODED 27 21 24 22 23 25 26 20 19 WB ADJ FPGA CONTROL SYNC PROCESSING DISCHARGE CONTROL FLASH CONTROL LVDS FPGA,ASIC IC9500 C1ZBZ0002599 15 13 17 11 14 16 12 31 32 33 34 35 36 37 38 MODEL SELECTION D-BOARD TNPA3820AJ(3/8) TH-42PV65C D-Board (3 of 8) Schematic Diagram TH-42PV65C D-Board (3 of 8) Schematic Diagram 100 14.39.D 电路板 （4/8）线路图 FP_UMH FP_NUEL FP_USL FP_UML UMH USH NUEL UML URL FP_URL FP_USH USL L8R_RI3 L8R_BI0 L8R_BI1 L8R_BI5 L8R_GI9 L8R_GI5 L8R_GI6 L8R_GI8 L8R_GI1 L8R_GI3 L8R_GI2 L8R_GI0 L8R_GI4 L8R_RI5 L8R_RI1 L8R_RI2 L8R_RI8 L8R_RI6 L8R_RI9 L8R_RI7 L8R_RI0 L8R_RI4 L8R_BI6 L8R_BI9 L8R_BI8 L8R_BI7 L8R_BI3 L8R_BI4 L8R_BI2 L8R_GI7 L8_PCK L8_OCK R8_OCK R8_PCK DD_ODED_R DD_PCD2 ODED_R D-PCD2 D-CLRD ODED_L DD_ODED_L L8L_UB07 L8L_UA05 L8L_UC06 L8L_UB09 L8L_UB05 L8L_UC09 L8L_UA09 L8L_UC08 L8L_UC11 L8L_UC07 L8L_UB11 L8L_UA08 L8L_UB10 L8L_UA07 L8L_UA10 L8L_UC10 L8L_UA11 L8L_UB06 L8L_UA06 L8L_UB08 L8L_UC05 BUS_SW BUS_SW BUS_SW BUS_SW L8L_UB12 L8L_UA15 L8L_DC15 L8L_UA12 L8L_DA14 L8L_DA15 L8L_UC12 L8L_UC13 L8L_DB15 DD_CLRD D-LED D-PCD1 FP_URH FP_UEH DD_LED DD_PCD1 URH UEH C0JBAZ000856 IC9503 G1 1 2 A1 3 A2 4 A3 5 A4 6 A5 7 A6 8 A7 9 A8 10 GND 11 Y8 12 Y7 13 Y6 14 Y5 15 Y4 16 Y3 17 Y2 18 Y1 19 G2 20 Vcc C9514 16V 1u C9547 50V 12p X9500 H0J200500038 C1ZBZ0003186 IC9200 XT 1 2 SL0 3 SL1 4 CLK9 5 VDD1 6 VSS1 7 CLK1 8 N/C 9 CLK2 10 VSS 11 N/C 12 CLK7 13 CLK6 14 CLK5 15 VSS2 16 VDD2 17 SL2 18 STBY 19 VDD3 20 XTN L9503 G1C150KA0038 R9625 10k R9633 47 C9548 16V 0.1u R9641 47 P3.3V R9643 0 R9632 47 C9546 50V 12p C9557 16V 1u C9552 16V 0.1u R9626 10k R9639 47 R9527 EXB2HV272JV R9628 10k R9428 EXB38V103JV R9637 47 C9554 6.3V 10u R9622 0 R9634 47 C0JBAZ000856 IC9505 G1 1 2 A1 3 A2 4 A3 5 A4 6 A5 7 A6 8 A7 9 A8 10 GND 11 Y8 12 Y7 13 Y6 14 Y5 15 Y4 16 Y3 17 Y2 18 Y1 19 G2 20 Vcc R9631 EXB2HV272JV C9542 16V 0.1u C0JBAZ002614 IC9402 1 NC 2 A0 3 A1 4 A2 5 A3 6 A4 7 A5 8 A6 9 A7 10 GND 11 NC 12 A8 13 A9 14 A10 15 A11 16 A12 17 A13 18 A14 19 A15 20 GND 21 NC 22 A16 23 A17 24 A18 25 A19 26 A20 27 A21 28 A22 29 A23 30 GND 31 NC 32 A24 33 A25 34 A26 35 A27 36 A28 37 A29 38 A30 39 A31 40 GND 41 B31 42 B30 43 B29 44 B28 45 B27 46 B26 47 B25 48 B24 49 OE4 50 VCC 51 B23 52 B22 53 B21 54 B20 55 B19 56 B18 57 B17 58 B16 59 OE3 60 VCC 61 B15 62 B14 63 B13 64 B12 65 B11 66 B10 67 B9 68 B8 69 OE2 70 VCC 71 B7 72 B6 73 B5 74 B4 75 B3 76 B2 77 B1 78 B0 79 OE1 80 VCC P5V P5V CPG 20SSMHz 60SSMHz 36.6MHz 84MHz 20MHz 39.5MHz 28 33 36 32 31 30 29 34 35 LEVEL CONVERTER LEVEL CONVERTER CLOCK GENE. 51 52 53 54 55 37 33 34 35 32 38 31 36 BUS SWITCH D-BOARD TNPA3820AJ(4/8) TH-42PV65C D-Board (4 of 8) Schematic Diagram TH-42PV65C D-Board (4 of 8) Schematic Diagram 101 14.40.D 电路板 （5/8）线路图 + G G G G G G G G SIDE TERM G G G G L8R_DB01 L8R_BI4 L8R_UC02 L8R_RI0 L8R_BI3 L8R_DQ6 L8R_TEST0 L8R_DQ16 L8R_NSDCLKO L8R_DC04 L8R_DQ5 L8R_UC01 L8R_GI4 L8R_RI8 L8R_GI2 L8R_BA1 L8R_BI6 L8R_K_TEST L8R_DC03 L8R_SDSEL L8R_UC00 L8R_DQ11 L8R_DQS2 L8R_DB00 L8R_RI2 L8R_OCKOUT L8R_DB08 L8R_DC02 L8R_TIIC L8R_DA01 L8R_DQ23 L8R_DQ20 L8R_DQ29 L8R_UA01 L8R_DC01 L8R_DA02 L8R_DA11 L8R_WE L8R_UA02 L8R_DB10 L8R_DQ22 L8R_BI9 L8R_DC00 L8R_TEST1 L8R_GI8 L8R_MUTE L8R_GI9 L8R_DRVCLKD3 L8R_DA10 L8R_BI1 L8R_TILD L8R_DQ2 L8R_A9 L8R_A6 L8R_DQ8 L8R_SDCLKO L8R_DRVCLKD2 L8R_RI7 L8R_BA0 L8R_DQS3 L8R_A2 L8R_DA03 L8R_DRVCLKD1 L8R_RI4 L8R_DQ31 L8R_RI3 L8R_A10 L8R_UB00 L8R_A0 L8R_DRVCLKD0 L8R_DA00 L8R_RI5 L8R_DB06 L8R_DB03 L8R_DQ30 L8R_DRVCLKU3 L8R_TCKSEL1 L8R_TCKSEL0 L8R_A11 L8R_DA05 L8R_DRVCLKU2 L8R_RI1 L8R_BI7 L8R_DA04 L8R_DRVCLKU1 L8R_DQ12 L8R_A4 L8R_GI1 L8R_TCPOUT L8R_DRVCLKU0 L8R_DA08 L8R_DQ27 L8R_UB02 L8R_DQ1 L8R_DA06 L8R_BI2 L8R_BI5 L8R_DC11 L8R_BI0 L8R_DQS1 L8R_UB04 L8R_RAS L8R_DQ21 L8R_DC10 L8R_DQ17 L8R_UA03 L8R_CS L8R_DB07 L8R_DQ25 L8R_DB02 L8R_RI9 L8R_DC09 L8R_DQS0 L8R_DQ18 L8R_MASK L8R_TCKSEL0 L8R_DB05 L8R_ID0 L8R_DQ3 L8R_DC08 L8R_A8 L8R_DA09 L8R_UA00 L8R_DQ24 L8R_DQ13 L8R_DC07 TCK L8R_SDIV0 L8R_DQ10 L8R_DB09 L8R_MONOUT2 L8R_K_TEST L8R_UB03 L8R_DC06 L8R_DQ14 L8R_A3 L8R_DC05 L8R_A5 TMS L8R_A1 L8R_RI6 L8R_DQ15 L8R_GI3 L8R_ID0 L8R_DQ4 L8R_DB04 L8R_DQ28 L8R_DQ7 L8R_GI0 L8R_SDIV1 L8R_GI5 L8R_A7 L8R_GI6 L8R_BI8 L8R_TCKSEL2 L8R_DQ0 L8R_CAS L8R_GI7 L8R_DA07 L8R_DQ9 L8R_UC04 L8R_DQ26 L8R_SDCKE L8R_UB01 L8R_FULL1 L8R_MUTE L8R_UC03 L8R_DQ19 L8R_MONOUT0 L8R_DB11 L8R_TEST0 L8R_TCKSEL1 L8R_TCKSEL2 L8R_TEST1 L8L_DB09 L8L_DC08 L8L_DC09 L8L_DA08 L8L_DB08 L8L_DA09 L8L_DB11 L8L_DC10 L8L_DC11 L8L_DA11 L8L_DA10 L8L_DB10 L8R_DA00 L8R_DA01 L8R_DB01 L8R_DC01 L8R_DC00 L8R_DB00 L8R_DC03 L8R_DB03 L8R_DA03 L8R_DC02 L8R_DB02 L8R_DA02 L8R_DC05 L8R_DB05 L8R_DA05 L8R_DC04 L8R_DB04 L8R_DA04 L8R_DC07 L8R_DA07 L8R_DB07 L8R_DC06 L8R_DA06 L8R_DB06 L8R_DC09 L8R_DA09 L8R_DB09 L8R_DC08 L8R_DA08 L8R_DB08 L8R_DC11 L8R_DA11 L8R_DB11 L8R_DC10 L8R_DA10 L8R_DB10 DOUTDA9 DOUTDB8 DOUTDB9 DOUTDA8 DOUTDC8 DOUTDC9 DOUTDB10 DOUTDB11 DOUTDA11 DOUTDA10 DOUTDC11 DOUTDC10 DOUTDB12 DOUTDB13 DOUTDA13 DOUTDA12 DOUTDC13 DOUTDC12 DOUTDB14 DOUTDB15 DOUTDA15 DOUTDA14 DOUTDC15 DOUTDC14 DOUTDC17 DOUTDA17 DOUTDB17 DOUTDC16 DOUTDA16 DOUTDB16 DOUTDC19 DOUTDA19 DOUTDB19 DOUTDC18 DOUTDA18 DOUTDB18 DOUTDC21 DOUTDA21 DOUTDB21 DOUTDC20 DOUTDA20 DOUTDB20 DOUTDC23 DOUTDA23 DOUTDB23 DOUTDC22 DOUTDA22 DOUTDB22 CLKD3_L CLKD2_L CLKD2_L CLKD3_L DOUTDC9 DOUTDA8 DOUTDB9 DOUTDB8 DOUTDA9 DOUTDC8 DOUTDA11 DOUTDB11 DOUTDC11 DOUTDC13 DOUTDA12 DOUTDA13 DOUTDB13 DOUTDC10 DOUTDA10 DOUTDB10 DOUTDC12 DOUTDB12 CLKD0_R CLKD1_R CLKD0_R CLKD1_R DOUTDC14 DOUTDC15 DOUTDA14 DOUTDB17 DOUTDA15 DOUTDA17 DOUTDB15 DOUTDB14 DOUTDB16 DOUTDA16 DOUTDC16 DOUTDC17 LED PCD2 CLRD_R ODED_RR LED PCD2 CLRD_R ODED_RR CLKD2_R CLKD3_R CLKD3_R CLKD2_R DOUTDA18 DOUTDC18 DOUTDB19 DOUTDA19 DOUTDC19 DOUTDB21 DOUTDA21 DOUTDB18 DOUTDA22 DOUTDB20 DOUTDB23 DOUTDA23 DOUTDA20 DOUTDC20 DOUTDC21 DOUTDC23 DOUTDC22 DOUTDB22 L8L_DRVCLKD2 L8L_DRVCLKD3 L8R_DRVCLKD0 L8R_DRVCLKD1 L8R_DRVCLKD3 L8R_HDI L8R_VDI D-PCD2 D-LED D-CLRD ODED_R 5V_DET4 5V_SENSE AA_XCE_R TDO_TO_FPGA TDO_TO_68_R SFRST SFVRST LATCH FULL0 P3V_SDA02 P3V_SCL02 L8R_UA04 L8R_UB05 L8R_UB06 L8R_UB07 L8R_UB08 L8R_UB09 L8R_UB10 L8R_UB11 L8R_UA05 L8R_UA06 L8R_UA07 L8R_UA08 L8R_UA09 L8R_UA10 L8R_UA11 L8R_UC05 L8R_UC06 L8R_UC07 L8R_UC08 L8R_UC09 L8R_UC10 L8R_UC11 L8R_DCK R8_PCK R8_OCK 5V_DET4 L8R_FULL1 L8R_DRVCLKD2 TRST L8L_DC15 L8L_UA15 L8L_DA14 L8L_DB15 L8L_UC15 L8L_UB14 L8L_UC13 L8L_UC12 L8L_UC14 L8L_UA14 L8L_UB15 L8L_UA13 L8L_UB12 L8L_DA15 L8L_UA12 L8L_UB13 XRST2 L8R_SDIV0 L8R_SDIV1 L8R_TIIC L8R_TILD L8R_MONOUT1 IC9400 P21 DOUTDC08 IC9400 D3 VDD12 IC9400 F2 BI1 IC9400 Y11 DQ24 IC9400 Y21 VDD33 TP011 IC9400 B20 DOUTUA03 IC9400 L14 VSS C9539 56u 4V IC9400 AA11 DQ30 IC9400 K12 VSS IC9400 P9 VSS TP061 R9437 10k IC9400 Y19 VSS IC9400 AB15 AVDD33_1 IC9400 AB18 DOUTDC00 IC9400 J13 VSS IC9400 E19 DOUTUC03 IC9400 V21 DOUTDC03 IC9400 G3 BI4 IC9400 D18 DOUTUC05 TP014 C9442 0.1u 16V D9401 MA3X152K0L IC9400 A10 SFLATCH C9460 0.1u 16V IC9400 D9 TCKSEL1 IC9400 H4 BI7 IC9400 E1 BI0 IC9400 N14 VSS IC9400 D15 DOUTUB08 IC9400 N13 VSS IC9400 A5 RI2 IC9400 C17 DOUTUA06 IC9400 AB3 NCK P1.2V TP047 IC9400 E15 VDD12 IC9400 V12 VDD25 IC9400 F1 BI3 IC9400 V3 DQ4 R9451 22 C9534 6.3V 10u IC9400 D17 DOUTUC06 IC9400 E11 VDD33 TP018 IC9400 M11 VSS IC9400 R19 DOUTDA05 IC9400 B6 RI1 IC9400 L22 DOUTDB11 IC9400 MN84521-A A1 VSS IC9400 AA8 A5 P2.5V IC9400 W2 DQ1 IC9400 F20 DOUTUB00 TP013 IC9400 R18 VDD33 IC9400 Y7 A0 IC9400 R5 VDD25 P3.3V IC9400 Y14 DQ12 C9458 0.1u 16V IC9400 Y3 VSS R9463 EXB38V470JV IC9400 E16 VDD12 C9541 50V 0.01u IC9400 V20 DOUTDB02 IC9400 W11 DQ25 IC9400 B15 DOUTUB10 C9468 0.1u 16V IC9400 G22 DRVCLKD0 IC9400 D2 GI4 IC9400 P19 DOUTDB07 IC9400 AA17 SDIV0 IC9400 A18 DOUTUB07 R9480 0 C9496 16V 0.1u IC9400 AA22 VSS IC9400 V18 VSS IC9400 L20 DOUTDC12 C9467 0.1u 16V IC9400 P11 VSS C9450 0.1u 16V L8R1.2V R9455 EXB2HV470JV IC9400 G21 DRVCLKD2 IC9400 A3 GI0 TP035 IC9400 A8 TCKSEL0 IC9400 W15 TCPOUT C9536 6.3V 10u IC9400 N19 DOUTDB09 P5V R9438 10k IC9400 W5 AVDD25_3 IC9400 N3 TDI IC9400 C21 DOUTUA02 IC9400 W19 VSS IC9400 F22 DRVCLKD3 L8R2.5V IC9400 A7 K_TEST TP007 C9513 0.1u 16V IC9400 E21 DOUTUA00 R9466 47 IC9400 AA20 DOUTDA01 IC9400 J4 ENHMASK TP054 IC9400 V2 DQ3 IC9400 T2 DQ20 IC9400 A13 DOUTUC13 IC9400 R20 DOUTDB06 IC9400 V5 VSS J0HABH000013 FL9502 IC9400 P2 XRST IC9400 N1 TRST IC9400 W8 A2 IC9400 AB14 DQ8 IC9400 C10 SFVRST IC9400 D11 DOUTUA15 IC9400 B5 RI5 IC9400 T19 DOUTDC04 IC9400 V13 VDD12 IC9400 AB11 DQ28 TP038 IC9400 K5 VDD33 TP029 IC9400 L18 VDD12 TP060 TP032 IC9400 J19 DOUTDA15 TP048 TP057 IC9400 F5 VDD12 TP036 IC9400 T3 AVDD25_1 R9459 47 IC9400 G18 VSS C9445 0.1u 16V IC9400 M9 VSS IC9400 T18 VDD33 TP045 TP021 L8R2.5V TP024 IC9400 L1 SCL IC9400 B13 DOUTUA12 IC9400 AA3 CK R9465 22 C9462 0.1u 16V IC9400 D16 DOUTUC07 IC9400 V9 VSS C9448 0.1u 16V C9447 0.1u 16V IC9400 V7 VDD25 IC9400 D7 RI3 IC9400 C13 DOUTUB12 IC9400 W13 DQ15 IC9400 T5 AVSS_2 IC9400 U2 AVSS_1 IC9400 M3 FULL1 IC9400 M1 TILD IC9400 J3 MONOUT0 TP005 IC9400 F18 VSS IC9400 Y15 VSS IC9400 E20 DOUTUC02 FL9401 J0HABH000013 1 2 3 IC9400 B3 GI1 IC9400 N2 TCK IC9400 B19 DOUTUA04 IC9400 G20 DRVCLKU1 IC9400 V17 VDD33 IC9400 M21 DOUTDB10 IC9400 W14 DQ13 IC9400 W7 NCS IC9400 B12 DOUTUC14 IC9400 L13 VSS IC9400 U21 DOUTDB04 R9472 100k IC9400 J9 VSS TP031 IC9400 V11 VDD25 TP026 IC9400 M2 FULL0 IC9400 J21 DOUTDB14 R9433 10k IC9400 W12 AVDD25_4 IC9400 C16 DOUTUC08 IC9400 M13 VSS IC9400 Y10 DQ26 IC9400 V22 DOUTDA03 IC9400 H21 DOUTDB15 TP009 IC9400 T21 DOUTDB05 IC9400 H3 BI8 IC9400 D6 RI7 IC9400 C1 VDD12 IC9400 A6 OCKOUT IC9400 N12 VSS IC9400 P22 DOUTDB08 FL9403 F1J1E1040022 1 2 3 IC9400 K20 DOUTDB13 IC9400 L11 VSS L8R1.2V TP041 IC9400 Y18 VSS IC9400 K21 DOUTDC13 IC9400 N20 DOUTDC09 IC9400 J12 VSS R9456 EXB2HV470JV IC9400 G4 BI2 IC9400 AB5 BA1 IC9400 C8 TEST0 IC9400 W10 DQ27 IC9400 P4 DQ18 C9461 0.1u 16V IC9400 A14 DOUTUA11 IC9400 J14 VSS IC9400 AB10 DQ29 IC9400 P5 VDD33 TP059 C9537 6.3V 10u IC9400 H20 DRVCLKD1 IC9400 AA2 VSS IC9400 W9 A10 IC9400 H19 DRVCLKU0 IC9400 C15 DOUTUB09 IC9400 K9 VSS IC9400 J2 MONOUT1 IC9400 M4 PCK IC9400 AA9 A8 IC9400 C14 DOUTUC11 C9456 0.1u 16V IC9400 E8 VDD12 C9446 0.1u 16V IC9400 E3 GI5 IC9400 E9 VDD33 IC9400 J18 VDD33 TP062 IC9400 W22 DOUTDC02 IC9400 P14 VSS IC9400 K2 VDI IC9400 N22 DOUTDA09 IC9400 E22 DRVCLKU3 IC9400 AB6 A4 IC9400 W17 VSS IC9400 U4 DQ5 IC9400 AA18 DOUTDB00 R9464 22 TP051 TP010 IC9400 B9 FPCLK TP052 TP030 L8R3.3V IC9400 V8 VDD25 C9463 0.1u 16V IC9400 R21 DOUTDA06 IC9400 N11 VSS IC9400 T1 DQ21 IC9400 Y2 VDD25 IC9400 AA7 A9 IC9400 AB19 DOUTDA00 IC9400 K10 VSS IC9400 E5 VSS IC9400 Y12 AVSS_4 IC9400 H5 VDD12 IC9400 C2 VDD12 IC9400 AB12 DQS1 IC9400 P20 DOUTDA07 IC9400 A17 DOUTUA08 IC9400 E17 VSS IC9400 N10 VSS IC9400 D14 DOUTUC10 IC9400 L10 VSS IC9400 K19 DOUTDC14 C9449 0.1u 16V R9452 22 IC9400 Y5 NCAS TP019 IC9400 R2 DQ23 IC9400 Y20 VSS TP016 IC9400 AA6 A11 IC9400 J10 VSS IC9400 AA5 CKE IC9400 H18 VDD33 IC9400 D8 OCK IC9400 U18 VDD33 IC9400 D13 DOUTUC12 IC9400 E18 VSS TP022 IC9400 H2 BI9 IC9400 R3 DQ17 IC9400 U20 DOUTDB03 TP025 TP028 IC9400 AA12 DQS3 IC9400 W18 VSS IC9400 P1 TDO IC9400 F19 DOUTUA01 FL9404 F1J1E1040022 1 2 3 IC9400 B16 DOUTUC09 C9444 0.1u 16V IC9400 W6 NWE IC9400 C22 DOUTUB01 IC9400 B21 VSS IC9400 AB20 DOUTDB01 IC9400 L5 VDD33 IC9400 AB4 BA0 TP053 R9485 1k IC9400 M22 DOUTDC10 IC9400 AA10 DQ31 IC9400 D21 DOUTUB02 R9454 EXB2HV470JV IC9400 P18 VDD33 IC9400 M5 VDD33 IC9400 L4 TIIC IC9400 AB22 VSS IC9400 Y9 A3 IC9400 E7 VDD12 IC9400 D5 GI2 L8R3.3V C9465 0.1u 16V IC9400 A19 DOUTUA05 C9443 0.1u 16V IC9400 N4 TMS IC9400 M19 DOUTDC11 IC9400 V1 DQS0 IC9400 C5 RI9 C9466 0.1u 16V IC9400 C7 RI0 IC9400 K22 DOUTDA12 IC9400 E4 VDD12 IC9400 AB17 VSS D34 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60 61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80 IC9400 E14 VDD33 IC9400 D22 DOUTUC01 IC9400 A9 FPDAT1 IC9400 U1 DQS2 IC9400 D19 VSS IC9400 V14 VDD12 IC9400 A22 VSS TP033 IC9400 AA13 DQ11 IC9400 A21 VSS IC9400 C12 DOUTUB13 IC9400 V15 VDD12 R9484 1k IC9400 W20 VDD33 C9533 0.1u 16V IC9400 L12 VSS FL9402 F1J1E1040022 1 2 3 IC9400 W3 VDD25 L8R3.3V IC9400 C18 DOUTUB05 TP027 TP056 L8R3.3V IC9400 B18 DOUTUB06 IC9400 C9 ROMCE IC9400 K1 DCK R9430 10k IC9400 A20 DOUTUC04 IC9400 W4 VSS IC9400 P13 VSS IC9400 D20 DOUTUB03 TP003 IC9400 U3 DQ6 IC9400 V19 VDD33 IC9400 M10 VSS IC9400 B10 SFRST IC9400 L9 VSS R9458 47 TP037 R9462 EXB38V470JV L8R2.5V TP040 IC9400 A2 VSS IC9400 K13 VSS IC9400 AA21 VSS TP004 TP008 IC9400 B17 DOUTUA07 R9514 0 IC9400 AB7 A6 C9457 0.1u 16V TP042 TP050 IC9400 V10 VDD25 IC9400 J5 VDD12 IC9400 R1 DQ22 IC9400 N9 VSS C9464 0.1u 16V IC9400 A15 DOUTUA10 IC9400 F4 GI7 IC9400 B8 TCKSEL2 IC9400 U22 DOUTDC05 C9459 0.1u 16V IC9400 D4 VSS IC9400 T20 DOUTDA04 IC9400 G19 DOUTUC00 IC9400 B1 VSS TP015 IC9400 G2 BI5 IC9400 M18 VDD12 IC9400 C20 VSS IC9400 AA14 DQ9 IC9400 K11 VSS IC9400 R4 DQ16 IC9400 U5 VDD25 IC9400 L21 DOUTDA11 IC9400 C11 DOUTUB15 IC9400 J22 DOUTDA13 IC9400 T22 DOUTDC06 IC9400 AA1 VDD25 IC9400 AA16 AVSS2 IC9400 K18 VDD33 TP049 IC9400 Y1 DQ0 IC9400 K14 VSS J0HABH000013 FL9501 IC9400 W21 VDD33 IC9400 M14 VSS IC9400 AB1 VSS C9469 0.1u 16V IC9400 N21 DOUTDA08 IC9400 R22 DOUTDC07 C9535 6.3V 10u IC9400 AB9 VDD25 IC9400 AB8 A7 TP039 C9454 0.1u 16V IC9400 A12 DOUTUB14 IC9400 D1 GI6 TP006 IC9400 C3 VSS C9538 6.3V 10u L8R3.3V IC9400 AB16 AVDD33_2 IC9400 P12 VSS IC9400 AB13 DQ10 IC9400 G1 BI6 TP046 Q9402 B1ABCF000138 TP020 TP058 IC9400 AA15 AVSS1 C9451 0.1u 16V IC9400 AA19 DOUTDC01 R9467 47 TP017 P3.3V IC9400 M20 DOUTDA10 IC9400 B22 VSS IC9400 B2 VSS IC9400 B4 RI8 IC9400 AA4 VREF IC9400 Y4 AVDD25_2 IC9400 Y22 VDD33 IC9400 Y17 VSS IC9400 AB2 VSS IC9400 G5 VDD12 IC9400 E6 VSS IC9400 E2 GI8 IC9400 D10 FPDAT0 IC9400 E10 VDD33 IC9400 P10 VSS IC9400 E12 VDD33 L8R2.5V IC9400 A4 RI6 TP023 IC9400 N18 VDD12 TP044 C9453 0.1u 16V IC9400 C6 RI4 IC9400 E13 VDD33 TP043 IC9400 Y13 DQ14 IC9400 H22 DOUTDA14 IC9400 C4 GI3 IC9400 U19 DOUTDA02 IC9400 F6 VSS IC9400 Y16 SDSEL IC9400 F3 GI9 R9461 22 IC9400 V16 VDD33 R9453 EXB2HV470JV IC9400 AB21 VSS L8R3.3V R9457 EXB2HV470JV IC9400 B7 TEST1 TP012 IC9400 L3 ID1 IC9400 A11 DOUTUA14 IC9400 H1 MUTE L8R3.3V IC9400 L19 DOUTDB12 IC9400 Y8 A1 IC9400 B14 DOUTUB11 IC9400 N5 VDD33 IC9400 A16 DOUTUA09 R9460 22 IC9400 W16 SDIV1 IC9400 L2 ID0 IC9400 D12 DOUTUA13 IC9400 J20 DOUTDC15 IC9400 K3 SDA C9512 0.1u 16V IC9400 F21 DRVCLKU2 IC9400 M12 VSS C9452 0.1u 16V R9470 4.7k R9471 10k IC9400 Y6 NRAS TP034 TP055 IC9400 V4 VDD25 IC9400 V6 AVSS_3 IC9400 J1 MONOUT2 IC9400 W1 DQ2 IC9400 K4 HDI C9455 0.1u 16V IC9400 P3 DQ19 IC9400 J11 VSS IC9400 T4 DQ7 IC9400 B11 DOUTUC15 TP002 R9539 0 IC9400 C19 DOUTUB04 to DDR from FPGA1 IIC from FPGA MN84521 Right DOUTDA[12] ODED DOUTDA[13] DOUTDB[11] DOUTDB[8] DOUTDC[13] GND DOUTDC[9] DOUTDB[13] CLK[2](+)_L GND DOUTDC[8] DOUTDA[11] LED PCD2 GND DOUTDA[8] CLK[3](-)_L DOUTDA[9] DOUTDB[9] DOUTDC[10] DOUTDC[11] DOUTDA[10] GND CLRD DOUTDB[10] GND DRV_RST GND DOUTDB[12] DOUTDC[14] DOUTDB[15] 5V_DET DOUTDA[14] DOUTDA[15] DOUTDC[12] DOUTDB[14] DOUTDC[15] GND N.C P5V P5V P5V P5V CLK[0](+)_R CLK[1](-)_R DOUTDA[17] DOUTDB[16] DOUTDC[17] GND DOUTDC[16] DOUTDB[17] DOUTDA[16] CLK[3](-)_R CLK[2](+)_R GND DOUTDC[22] GND DOUTDA[22] DOUTDC[23] DOUTDC[19] DOUTDB[23] DOUTDC[18] DOUTDA[21] GND DOUTDA[18] DOUTDA[19] DOUTDB[19] DOUTDC[20] DOUTDC[21] DOUTDA[20] DOUTDB[20] DOUTDA[23] DOUTDB[21] DOUTDB[18] GND DOUTDB[22] GND GND rromdata[00] rromdata[03] rromdata[01] rromdata[2] rromdata[12] rromdata[15] rromdata[09] rromdata[06] rromdata[05] rromdata[14] rromdata[08] rromdata[11] rromdata[04] rromdata[07] rromdata[10] rromdata[13] rromadrs[20] rromadrs[02] rromadrs[05] rromadrs[08] rromadrs[11] rromadrs[14] rromadrs[17] rromadrs[07] rromadrs[10] rromadrs[13] rromadrs[01] rromadrs[16] rromadrs[19] rromadrs[04] rromadrs[03] rromadrs[06] rromadrs[09] rromadrs[12] rromadrs[15] rromadrs[18] rromadrs[00] N.C rromadrs[-1] 42 45 37 41 39 40 44 38 43 to FPGA PLASMA AI RGB PROCESSOR FORMAT CONVERTER IC9400 SUB FIELD PROCESSOR MN84521-A(LSI58) DATA DRIVER RIGHT TO (C11) C1-BOARD 53 52 55 51 54 61 62 63 64 65 66 D-BOARD TNPA3820AJ(5/8) TH-42PV65C D-Board (5 of 8) Schematic Diagram TH-42PV65C D-Board (5 of 8) Schematic Diagram 102 14.41.D 电路板 （6/8）线路图 G G + TERM SIDE L8R_DQ4 L8R_DQ3 L8DR_DQ30 L8DR_A0 L8DR_DQS2 L8R_A4 L8DR_DQ4 L8R_DQ21 L8R_DQ17 L8DR_DQ20 L8R_DQS1 L8DR_DQ25 L8DR_DQ26 L8DR_DQ23 L8DR_A0 L8DR_DQ9 L8DR_A2 L8R_DQ25 L8DR_DQ8 L8R_DQ15 L8DR_NCLK L8DR_DQ14 L8R_WE L8R_A3 L8R_DQ26 L8DR_DQ18 L8R_DQ18 L8DR_A4 L8DR_DQ6 L8R_DQ12 L8DR_DQ29 L8DR_A10 L8DR_DQ30 L8R_DQ9 L8DR_CKE L8R_DQ10 L8DR_NCS L8DR_DQ22 L8R_BA0 L8DR_DQS3 L8DR_DQ29 L8R_DQS3 L8R_DQ0 L8DR_DQ20 L8R_A2 L8DR_CLK L8DR_DQ15 L8DR_DQ21 L8DR_A7 L8DR_DQ7 L8DR_A6 L8DR_DQ24 L8R_CS L8R_DQ28 L8R_DQ27 L8R_DQ29 L8DR_A5 L8DR_DQ16 L8DR_A5 L8R_DQ6 L8DR_DQ15 L8DR_DQ28 L8R_DQ19 L8DR_DQ1 L8DR_DQ2 L8R_BA1 L8R_DQ22 L8DR_DQ25 L8DR_BA0 L8DR_A11 L8DR_DQ31 L8R_CAS L8R_A6 L8DR_A4 L8DR_DQ10 L8R_DQ14 L8DR_A8 L8DR_NRAS L8DR_BA1 L8DR_BA0 L8DR_DQS3 L8DR_DQ18 L8R_DQ23 L8R_DQS0 L8DR_A11 L8DR_DQ11 L8DR_NCS L8DR_DQ24 L8DR_DQ5 L8DR_DQ31 2.5V L8DR_DQ8 L8DR_DQ6 L8DR_DQ21 L8DR_DQS1 L8DR_NCAS L8DR_A3 L8DR_DQ3 L8DR_DQ11 L8R_DQ11 L8DR_CKE L8R_A9 L8R_DQ5 L8R_DQS2 L8R_A11 L8DR_DQ10 L8R_A0 L8R_RAS L8DR_A9 L8DR_NWE L8R_DQ31 L8DR_DQ0 L8DR_A3 L8R_DQ30 L8DR_A6 L8DR_A10 L8DR_DQ27 L8DR_DQ13 L8R_DQ8 L8R_A8 L8DR_DQ26 L8DR_DQS1 L8R_SDCLKO L8R_DQ2 L8DR_A8 L8R_DQ16 L8R_DQ20 L8DR_DQ14 L8DR_NRAS L8DR_NWE L8DR_DQ5 L8DR_DQ13 L8DR_A9 L8DR_DQ3 L8DR_A1 L8R_DQ24 L8DR_DQ19 L8R_SDCKE L8R_A7 L8DR_A1 L8R_DQ13 L8R_A5 L8DR_DQS2 L8DR_DQS0 L8DR_DQ19 L8DR_DQ7 L8R_DQ1 L8DR_DQ27 L8DR_A2 L8DR_DQ28 L8R_A10 L8DR_A7 L8DR_BA1 L8DR_DQ17 L8DR_DQ16 L8R_DQ7 L8DR_DQ4 L8DR_DQS0 L8DR_DQ9 L8R_A1 L8DR_DQ1 L8DR_DQ12 L8DR_DQ17 L8R_NSDCLKO L8DR_DQ2 L8DR_DQ22 L8DR_NCAS L8DR_DQ23 L8DR_DQ12 L8DR_DQ0 L8L_UC09 L8L_UA09 L8L_UA11 L8L_UA08 L8L_UB11 L8L_UC08 L8L_UA10 L8L_UB09 L8L_UA05 L8L_UB10 L8L_UB05 L8L_UC05 AA_XOE AA_XCE_L L8L_UC07 L8L_UC11 AA_XWE L8L_UB07 L8L_UB08 AA_BYTE L8L_UA06 L8L_UC06 L8L_UC10 L8L_UA07 L8L_UB06 DOUTDB2 C_UML L8L_DC03 DOUTDC1 5V_SENSE DOUTDB3 L8L_DC04 L8L_DB00 L8L_DC05 DOUTDC7 DOUTDA1 L8L_DB04 L8L_DA04 L8L_DC07 ODED_L L8L_DC06 L8L_DA03 DOUTDC2 L8L_DB03 SOS8_SS DOUTDA2 DOUTDA3 D-LED L8L_DA07 L8L_DA06 DOUTDA0 L8L_DB02 C_UMH 5V_DET3 C_NUEL DOUTDA5 L8L_DA01 CLKD0_L LED_L DOUTDC5 DOUTDB4 D-PCD1 L8L_DB06 CLKD1_L DOUTDC6 DOUTDA6 PCD1 UEH DOUTDB5 L8L_DB07 USL ODED_LL USH C_DRV_SOS8 L8L_DA00 L8L_DB01 DOUTDB0 UML DOUTDC3 DOUTDB7 UMH L8L_DC02 DOUTDC4 CLRD_L DOUTDB1 L8L_DA02 L8L_DB05 DOUTDB6 NUEL D-CLRD C_UEH L8L_DC01 DOUTDA4 C_USL DOUTDC0 L8L_DC00 DOUTDA7 C_USH L8L_DA05 DOUTDA6 DOUTDA5 DOUTDC3 DOUTDA2 DOUTDC6 DOUTDB6 DOUTDA3 DOUTDA7 DOUTDB0 DOUTDC2 DOUTDB3 DOUTDB7 DOUTDA0 DOUTDC0 DOUTDC7 DOUTDB2 L8L_DRVCLKD0 L8L_DRVCLKD1 C_URH URH URL C_URL L8L_DC15 L8L_UA14 L8L_DA15 L8L_UC13 L8L_UC12 L8L_UB15 L8L_DA14 L8L_UC15 L8L_UA15 L8L_UC14 L8L_UA12 L8L_UB13 L8L_UB14 L8L_UB12 L8L_UA13 L8L_DB15 C_DMHR C_DMLL C_DMHL C_DSLL C_DSHL DOUTDB5 DOUTDC5 DOUTDA4 DOUTDB4 DOUTDC4 DOUTDC1 DOUTDB1 DOUTDA1 ODED_LL CLRD_L PCD1 LED_L CLKD1_L CLKD0_L C_DRV_SOS8 C_URL C_NUEL C_UMH C_UML C_USH C_USL C_UEH C_URH 5V_DET3 C_DRV_SOS7 F_RST L8DR_NCLK L8DR_CLK DRVRST IC9401 D9 VSS IC9401 C5 VSSQ L8R2.5V R9419 EXB38V470JV IC9401 B9 VDDQ FL9400 J0HABH000013 1 2 3 IC9401 F10 VDDQ C9473 16V 0.1u TP9414 R9412 EXB38V470JV IC9401 B11 VDDQ IC9401 E2 DQ16 TP9439 IC9401 B6 VDDQ IC9401 D6 VSS TP9407 IC9401 L5 A2 C9485 16V 0.1u C9482 16V 0.1u P3.3V TP9402 C9477 16V 0.1u IC9401 J4 VSSQ IC9401 F1 DQ19 TP9417 IC9401 C3ABQJ000051 A1 DQS0 R9404 EXB2HV470JV TP9400 IC9401 M11 CKE TP9411 IC9401 J2 DQ23 R9493 47 TP9426 IC9401 C7 VDD TP9431 IC9401 E11 DQ15 IC9401 B2 VDDQ IC9401 D8 VSSQ IC9401 D3 VDD TP9403 IC9401 J9 VSSQ IC9401 D12 DQ24 IC9401 K6 VDD IC9401 M9 A7 IC9401 L12 MCL IC9401 H9 VSSQ IC9401 L8 A5 R9450 EXB2HV470JV IC9401 E4 VSSQ IC9401 M8 A6 IC9401 M6 A3 C9491 16V 0.1u IC9401 J5 VSS IC9401 F12 DQ12 IC9401 L2 NC TP9453 IC9401 H1 DQ21 R9415 EXB38V470JV IC9401 M12 VREF IC9401 L9 RFU2 TP9429 C9472 16V 0.1u P3.3V IC9401 D10 VDD C9490 16V 0.1u IC9401 G10 NC R9645 0 R9468 100 TP9441 TP9448 IC9401 A3 VSSQ IC9401 A12 DQS3 IC9401 J12 DQ8 IC9401 E9 VSSQ IC9401 K8 RFU1 IC9401 K12 NC Q9401 B1ABCF000138 TP9419 IC9401 M10 A8/AP C9476 16V 0.1u IC9401 F8 VSS_Thermal IC9401 C2 DQ5 IC9401 C4 VSSQ TP9435 C9475 16V 0.1u C9494 16V 0.1u C9608 16V 0.1u TP9420 IC9401 G2 DM2 IC9401 K3 VDD IC9401 M2 NC TP9408 R9414 EXB38V470JV C9486 16V 0.1u IC9401 A2 DM0 IC9401 J10 VDDQ IC9401 J11 DQ9 TP9437 IC9401 K10 VDD R9620 4.7k TP9410 C9481 16V 0.1u R9443 100k IC9401 H8 VSS_Thermal TP9418 IC9401 A6 DQ0 R9442 10k IC9401 H6 VSS_Thermal IC9401 F6 VSS_Thermal IC9401 G12 DQS1 TP9451 TP9447 IC9401 H5 VSS_Thermal IC9401 H11 DQ11 TP9440 TP9409 C9492 16V 0.1u IC9401 G3 NC IC9401 A11 DM3 IC9401 E8 VSS_Thermal R9445 22 IC9401 C12 DQ25 TP9442 IC9401 B4 VDDQ C9487 16V 0.1u IC9401 B8 DQ30 IC9401 B1 DQ4 IC9401 L11 CK R9448 22 IC9401 F7 VSS_Thermal IC9401 F5 VSS_Thermal R9444 EXB2HV470JV TP9452 IC9401 D4 VSS R9440 EXB2HV470JV R9441 4.7k IC9401 E12 DQ14 IC9401 H2 DQ20 TP9449 R9482 1k IC9304 1 A15 2 A14 3 A13 4 A12 5 A11 6 A10 7 A9 8 A8 9 A19 10 NC 11 WE# 12 RESET# 13 NC 14 NC 15 RY/BY# 16 A18 17 A17 18 A7 19 A6 20 A5 21 A4 22 A3 23 A2 24 A1 25 A0 26 CE# 27 VSS 28 OE# 29 DQ0 30 DQ8 31 DQ1 32 DQ9 33 DQ2 34 DQ10 35 DQ3 36 DQ11 37 VCC 38 DQ4 39 DQ12 40 DQ5 41 DQ13 42 DQ6 43 DQ14 44 DQ7 45 DQ15/A-1 46 VSS 47 BYTE# 48 A16 IC9401 A4 DQ3 C9497 56u 4V TP9424 IC9401 G8 VSS_Thermal IC9401 D1 DQ7 C9470 16V 0.1u IC9401 H4 VSSQ TP9413 TP9422 C9484 16V 0.1u IC9401 K5 A10 C9488 16V 0.1u IC9401 M4 A0 TP9438 L8R2.5V IC9401 B12 DQ27 TP9446 IC9401 F11 DQ13 IC9401 C6 VDD IC9401 J7 VSS IC9401 D5 VSSQ TP9450 R9418 EXB38V470JV R9483 1k IC9401 D7 VSS TP9406 TP9423 TP9405 R9416 EXB38V470JV IC9401 F3 VDDQ IC9401 H3 VDDQ R9421 EXB38V470JV P5V TP9434 IC9401 E3 VDDQ IC9401 L3 NC IC9401 F2 DQ18 IC9401 K9 VSS D9400 MA3X152K0L R9616 0 IC9401 E6 VSS_Thermal C9480 16V 0.1u TP9454 TP9425 IC9401 K2 WE TP9433 C9601 16V 0.1u R9515 47 TP9428 R9494 47 IC9401 H12 DQ10 IC9401 B10 NC C9474 16V 0.1u TP9430 IC9401 F4 VSSQ IC9401 H7 VSS_Thermal IC9401 M7 A4 IC9401 L6 A11 IC9401 M5 A1 IC9401 L4 BA1 IC9401 A5 DQ2 IC9401 C1 DQ6 C9495 16V 0.1u TP9416 IC9401 G6 VSS_Thermal IC9401 E7 VSS_Thermal IC9401 K4 VSS IC9401 B5 DQ1 IC9401 G5 VSS_Thermal R9619 4.7k C9478 16V 0.1u IC9401 H10 VDDQ C9540 50V 0.01u IC9401 J1 DQ22 D33 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 57 58 59 60 61 62 63 64 65 66 67 68 56 IC9401 L7 A9 R9449 EXB2HV470JV C9489 16V 0.1u R9413 EXB38V470JV IC9401 K11 NC R9489 47 R9492 47 P3.3V IC9401 C9 VSSQ R9446 EXB38V470JV IC9401 M3 BA0 C9479 16V 0.1u R9486 33 IC9401 L10 CK IC9401 A10 VSSQ IC9401 D11 VDDQ IC9401 E5 VSS_Thermal L8R2.5V IC9401 E10 VDDQ IC9401 K7 VDD IC9401 J8 VSS R9487 150 IC9401 C11 DQ26 IC9401 G9 VSSQ TP9415 IC9401 K1 CAS TP9436 IC9401 C8 VSSQ IC9401 G1 DQS2 IC9401 C3 VSSQ C9493 16V 0.1u R9490 47 R9417 EXB38V470JV R9491 47 R9488 33 IC9401 G4 VSSQ IC9401 L1 RAS TP9432 TP9404 TP9421 IC9401 G11 DM1 R9495 47 IC9401 A9 DQ28 IC9401 A8 DQ29 IC9401 J6 VSS TP9427 IC9401 G7 VSS_Thermal IC9401 E1 DQ17 IC9401 F9 VSSQ IC9602 C0EBE0000066 1 NC 2 SUB 3 GND 5 Vcc 4 Vout R9420 EXB38V470JV IC9401 B7 VDDQ IC9401 M1 CS Q9400 B1ABCF000138 IC9401 A7 DQ31 IC9401 J3 VDDQ TP9445 C9483 16V 0.1u TP9455 IC9401 C10 VSSQ IC9401 D2 VDDQ R9469 100k IC9401 B3 NC TP9412 DDR-Terminate 16M FLASH MEMORY P5V GND GND UMH GND DRV_RST DOUTDA[3] DOUTDC[2] GND DOUTDB[4] DOUTDA[4] DOUTDB[0] DOUTDC[6] CLK[0](+)_L LED UEH DOUTDC[3] DOUTDB[3] DOUTDB[2] GND USH DOUTDA[2] CLRD ODED DOUTDA[5] C_URL DOUTDB[7] DOUTDC[5] P5V 5V_DET DOUTDC[1] DOUTDB[5] CLK[1](-)_L DOUTDA[6] USL UML DOUTDA[7] DOUTDC[4] P5V NUEL GND GND GND DOUTDC[0] PCD1 GND DOUTDA[0] DOUTDB[6] DOUTDC[7] P5V DRV_SOS8 DOUTDA[1] DOUTDB[1] GND N.C 47 50 53 51 54 48 46 49 52 DDR SDRAM_R(128M) IC9401 TO (C21) C2-BOARD 61 63 64 66 62 65 81 82 83 84 TVRN825-1 RESET TH-42PV65C D-Board (6 of 8) Schematic Diagram TH-42PV65C D-Board (6 of 8) Schematic Diagram D-BOARD TNPA3820AJ(6/8) 103 14.42.D 电路板 （7/8）线路图 G G G G G G G G G G L8L_DQ29 L8L_DQ2 L8L_DB03 L8L_BI9 L8L_A8 L8L_UB08 L8L_DC01 L8L_SDIV0 L8L_DA07 L8L_DQ28 L8L_DQ1 L8L_DB02 L8L_RI0 L8L_A7 L8L_UB09 L8L_DC02 L8L_DA06 L8L_DQ27 L8L_DQ0 L8L_DB01 L8L_RI1 L8L_A6 L8L_UB10 L8L_DC03 L8L_DA05 L8L_DQ26 L8L_DB00 L8L_RI4 L8L_A5 L8L_UB11 L8L_DC04 L8L_DA04 L8L_DQ25 L8L_RI2 L8L_UC11 L8L_A4 L8L_DC05 L8L_DA03 L8L_DQ24 L8L_VDI L8L_RI3 L8L_UC10 L8L_A3 L8L_DC06 L8L_DA02 L8L_DQ23 TMS L8L_HDI L8L_RI5 L8L_UC09 L8L_A2 L8L_DC07 L8L_DA01 L8L_DQ22 L8L_RI6 L8L_UC08 L8L_A1 L8L_DC08 L8L_DA00 L8L_DQ21 TCK L8L_GI0 L8L_RI7 L8L_UC07 L8L_A0 L8L_DC09 L8L_DQ20 L8L_GI1 L8L_RI8 L8L_UC06 L8L_DC10 L8L_DQ19 L8L_GI2 L8L_RI9 L8L_UC05 L8L_DC11 L8L_DQ18 L8L_TCKSEL2 L8L_GI3 L8L_UC04 L8L_DQ17 L8L_TCKSEL1 L8L_GI4 P3V_SCL02 L8L_UC03 L8L_DQ16 L8L_RAS L8L_TCKSEL0 L8L_GI5 L8L_UC02 L8L_DQ15 L8L_K_TEST L8L_GI6 L8L_UC01 L8L_DRVCLKD0 L8L_WE L8L_DQ14 L8L_TEST1 L8L_TIIC L8L_GI7 L8L_UC00 L8L_UA00 L8L_DRVCLKD1 L8L_DQ13 L8L_TEST0 L8L_TILD L8L_GI8 L8L_DRVCLKU1 L8L_UA01 L8L_CS L8L_DQ12 L8L_MUTE L8L_OCKOUT L8L_GI9 L8L_DRVCLKU0 L8L_UA02 L8L_DQ11 L8L_MONOUT2 L8L_BI0 L8L_CAS L8L_UA03 L8L_DQ10 L8L_MONOUT0 L8L_DB11 L8L_BI1 L8L_SDCKE L8L_UB00 L8L_UA04 L8L_DQ9 SFRST L8L_DB10 L8L_BI2 L8L_NSDCLKO L8L_UB01 L8L_UA05 L8L_DQS3 L8L_DQ8 SFVRST L8L_DB09 L8L_BI3 L8L_SDCLKO L8L_UB02 L8L_UA06 L8L_DQS2 L8L_DQ7 LATCH L8L_DB08 L8L_BI4 L8L_BA1 L8L_UB03 L8L_UA07 L8L_DQS1 L8L_DQ6 L8L_TCPOUT FPCLK L8L_DB07 L8L_BI5 L8L_BA0 L8L_UB04 L8L_UA08 L8L_DA11 L8L_DQS0 L8L_DQ5 FPDAT0 L8L_SDSEL L8L_DB06 L8L_BI6 L8L_A11 L8L_UB05 L8L_UA09 L8L_DA10 L8L_DQ31 L8L_DQ4 FPDAT1 L8L_DB05 L8L_FULL1 L8L_BI7 L8L_A10 L8L_UB06 L8L_UA10 L8L_DA09 L8L_DQ30 L8L_DQ3 L8L_MONOUT1 L8L_DB04 L8L_BI8 L8L_SDIV1 L8L_A9 L8L_UB07 L8L_DC00 L8L_UA11 L8L_DA08 L8L_TEST0 L8L_TEST1 L8L_TCKSEL2 L8L_DRVCLKD3 L8L_DRVCLKD2 L8L_DRVCLKU2 L8L_DRVCLKU3 L8L_MASK AA_XCE_L TDO_TO_68_R P3V_SDA02 TDI_TO_68_L L8L_DCK L8_PCK L8_OCK FULL0 L8L_FULL1 TRST L8L_UB13 L8L_UC15 L8L_DB15 L8L_UB12 L8L_UA12 L8L_UA13 L8L_UC13 L8L_DC15 L8L_UB14 L8L_UA14 L8L_DA15 L8L_UC12 L8L_UB15 L8L_UA15 L8L_DA14 L8L_UC14 L8L_SDIV0 L8L_SDIV1 L8L_MUTE L8L_K_TEST L8L_TCKSEL0 L8L_TCKSEL1 XRST L8L_TIIC L8L_TILD L8L1.2V IC9300 E19 DOUTUC03 IC9300 P5 VDD33 IC9300 AB22 VSS L8L1.2V IC9300 T21 DOUTDB05 IC9300 G3 BI4 IC9300 T4 DQ7 IC9300 W1 DQ2 L8L3.3V IC9300 AA1 VDD25 IC9300 D6 RI7 IC9300 AA8 A5 IC9300 R18 VDD33 IC9300 L13 VSS IC9300 C13 DOUTUB12 IC9300 K14 VSS IC9300 B14 DOUTUB11 IC9300 M9 VSS IC9300 P1 TDO IC9300 B21 VSS IC9300 Y11 DQ24 IC9300 A10 SFLATCH C9306 0.1u 16V IC9300 Y3 VSS IC9300 V7 VDD25 IC9300 K19 DOUTDC14 IC9300 AB19 DOUTDA00 IC9300 K20 DOUTDB13 IC9300 P11 VSS IC9300 P21 DOUTDC08 IC9300 V11 VDD25 IC9300 N2 TCK IC9300 V22 DOUTDA03 IC9300 H1 MUTE IC9300 N3 TDI IC9300 W14 DQ13 IC9300 A17 DOUTUA08 IC9300 AB11 DQ28 IC9300 C17 DOUTUA06 IC9300 R5 VDD25 IC9300 U20 DOUTDB03 IC9300 L18 VDD12 IC9300 W7 NCS IC9300 H21 DOUTDB15 IC9300 K18 VDD33 IC9300 U1 DQS2 IC9300 E3 GI5 IC9300 D9 TCKSEL1 C9316 0.1u 16V IC9300 AB13 DQ10 IC9300 J10 VSS IC9300 B18 DOUTUB06 L8L2.5V IC9300 H19 DRVCLKU0 P3.3V IC9300 AB8 A7 IC9300 W5 AVDD25_3 IC9300 N22 DOUTDA09 IC9300 Y14 DQ12 P1.2V IC9300 B16 DOUTUC09 C9300 0.1u 16V IC9300 H2 BI9 IC9300 MN84521-A A1 VSS IC9300 AB6 A4 IC9300 G1 BI6 R9475 10k IC9300 W13 DQ15 IC9300 J21 DOUTDB14 IC9300 F4 GI7 IC9300 F6 VSS IC9300 U18 VDD33 IC9300 F5 VDD12 IC9300 N13 VSS IC9300 C22 DOUTUB01 IC9300 U4 DQ5 IC9300 P13 VSS IC9300 AA14 DQ9 IC9300 C1 VDD12 IC9300 L10 VSS IC9300 W18 VSS C9365 56u 4V IC9300 A3 GI0 IC9300 D14 DOUTUC10 C9360 6.3V 10u IC9300 M19 DOUTDC11 R9512 0 IC9300 M3 FULL1 C9313 0.1u 16V L8L3.3V IC9300 D4 VSS C9305 0.1u 16V IC9300 Y20 VSS IC9300 M10 VSS IC9300 G5 VDD12 IC9300 V10 VDD25 IC9300 J14 VSS L8L3.3V FL9303 F1J1E1040022 1 2 3 IC9300 Y21 VDD33 C9322 0.1u 16V IC9300 Y18 VSS IC9300 V3 DQ4 IC9300 B10 SFRST IC9300 K11 VSS IC9300 G18 VSS IC9300 Y9 A3 IC9300 A19 DOUTUA05 L8R3.3V C9361 6.3V 10u IC9300 K9 VSS IC9300 E20 DOUTUC02 IC9300 H22 DOUTDA14 IC9300 J1 MONOUT2 TP9444 HIN IC9300 B8 TCKSEL2 IC9300 A18 DOUTUB07 IC9300 W2 DQ1 IC9300 F20 DOUTUB00 IC9300 W3 VDD25 C9314 0.1u 16V IC9300 C2 VDD12 P2.5V IC9300 C4 GI3 IC9300 K10 VSS IC9300 AB21 VSS C9304 0.1u 16V C9357 0.1u 16V IC9300 A16 DOUTUA09 IC9300 V15 VDD12 IC9300 J13 VSS IC9300 A6 OCKOUT IC9300 E13 VDD33 C9311 0.1u 16V IC9300 R2 DQ23 IC9300 AA18 DOUTDB00 IC9300 R1 DQ22 IC9300 D10 FPDAT0 L8L2.5V IC9300 H18 VDD33 IC9300 B13 DOUTUA12 IC9300 B1 VSS IC9300 P19 DOUTDB07 L8L3.3V IC9300 R19 DOUTDA05 C9324 0.1u 16V IC9300 C19 DOUTUB04 IC9300 P9 VSS IC9300 C14 DOUTUC11 IC9300 AB15 AVDD33_1 IC9300 M22 DOUTDC10 IC9300 R20 DOUTDB06 J0HABH000013 FL9305 IC9300 E8 VDD12 IC9300 M5 VDD33 IC9300 F1 BI3 IC9300 K2 VDI IC9300 G21 DRVCLKD2 IC9300 AA15 AVSS1 IC9300 C10 SFVRST IC9300 AA10 DQ31 R9581 1k IC9300 T20 DOUTDA04 IC9300 Y2 VDD25 C9362 6.3V 10u IC9300 M21 DOUTDB10 C9317 0.1u 16V IC9300 V13 VDD12 IC9300 AA19 DOUTDC01 IC9300 D15 DOUTUB08 IC9300 H20 DRVCLKD1 C9355 0.1u 16V IC9300 C12 DOUTUB13 IC9300 W20 VDD33 IC9300 B17 DOUTUA07 IC9300 Y6 NRAS R9578 0 IC9300 A12 DOUTUB14 C9356 0.1u 16V IC9300 P2 XRST IC9300 U2 AVSS_1 IC9300 V8 VDD25 IC9300 U5 VDD25 TP9443 VIN IC9300 A9 FPDAT1 IC9300 Y12 AVSS_4 IC9300 G19 DOUTUC00 IC9300 A7 K_TEST IC9300 M14 VSS IC9300 L1 SCL IC9300 F18 VSS IC9300 M1 TILD IC9300 A5 RI2 IC9300 A21 VSS IC9300 B2 VSS IC9300 P3 DQ19 IC9300 K21 DOUTDC13 IC9300 AB9 VDD25 IC9300 V17 VDD33 IC9300 W8 A2 C9321 0.1u 16V IC9300 B7 TEST1 IC9300 M2 FULL0 IC9300 Y22 VDD33 IC9300 D7 RI3 L8L3.3V IC9300 R22 DOUTDC07 IC9300 A20 DOUTUC04 IC9300 B3 GI1 IC9300 F2 BI1 C9310 0.1u 16V IC9300 W12 AVDD25_4 IC9300 Y4 AVDD25_2 IC9300 K3 SDA IC9300 T19 DOUTDC04 IC9300 D12 DOUTUA13 IC9300 G20 DRVCLKU1 IC9300 G2 BI5 IC9300 Y13 DQ14 IC9300 A13 DOUTUC13 L8L2.5V IC9300 U21 DOUTDB04 IC9300 B11 DOUTUC15 IC9300 G4 BI2 L8L2.5V IC9300 P12 VSS IC9300 M20 DOUTDA10 IC9300 AA16 AVSS2 R9389 10k IC9300 T1 DQ21 IC9300 N9 VSS IC9300 C9 ROMCE R9602 0 IC9300 W15 TCPOUT R9574 0 IC9300 D2 GI4 IC9300 K22 DOUTDA12 IC9300 N5 VDD33 IC9300 AB18 DOUTDC00 IC9300 A11 DOUTUA14 IC9300 J9 VSS IC9300 Y10 DQ26 C9368 16V 0.1u IC9300 M13 VSS IC9300 V18 VSS IC9300 K12 VSS IC9300 J12 VSS IC9300 P4 DQ18 IC9300 Y15 VSS IC9300 G22 DRVCLKD0 C9363 6.3V 10u C9364 6.3V 10u IC9300 AA13 DQ11 IC9300 C8 TEST0 IC9300 AA17 SDIV0 IC9300 E21 DOUTUA00 IC9300 E15 VDD12 IC9300 P14 VSS C9325 0.1u 16V IC9300 D3 VDD12 IC9300 AA12 DQS3 IC9300 U22 DOUTDC05 IC9300 N18 VDD12 IC9300 W22 DOUTDC02 IC9300 W11 DQ25 IC9300 E2 GI8 C9312 0.1u 16V IC9300 N20 DOUTDC09 IC9300 D21 DOUTUB02 IC9300 V19 VDD33 IC9300 A2 VSS IC9300 B20 DOUTUA03 IC9300 L9 VSS IC9300 V4 VDD25 IC9300 M4 PCK IC9300 E1 BI0 C9318 0.1u 16V IC9300 J4 ENHMASK IC9300 D18 DOUTUC05 C9320 0.1u 16V IC9300 N19 DOUTDB09 C9301 0.1u 16V IC9300 E12 VDD33 IC9300 H3 BI8 IC9300 J22 DOUTDA13 IC9300 W17 VSS IC9300 D22 DOUTUC01 C9307 0.1u 16V IC9300 V9 VSS IC9300 L12 VSS IC9300 AA5 CKE IC9300 E14 VDD33 IC9300 H5 VDD12 IC9300 E22 DRVCLKU3 IC9300 P10 VSS C9359 0.1u 16V IC9300 T2 DQ20 IC9300 J5 VDD12 IC9300 V20 DOUTDB02 IC9300 V16 VDD33 IC9300 T5 AVSS_2 IC9300 AA20 DOUTDA01 IC9300 P18 VDD33 FL9302 F1J1E1040022 1 2 3 C9315 0.1u 16V IC9300 AA6 A11 C9323 0.1u 16V IC9300 W9 A10 C9309 0.1u 16V IC9300 E16 VDD12 IC9300 F21 DRVCLKU2 IC9300 B12 DOUTUC14 IC9300 N1 TRST IC9300 L11 VSS C9308 0.1u 16V IC9300 N21 DOUTDA08 IC9300 AA7 A9 IC9300 U19 DOUTDA02 IC9300 J11 VSS IC9300 Y16 SDSEL IC9300 V21 DOUTDC03 IC9300 AA11 DQ30 R9367 180 IC9300 N11 VSS IC9300 D17 DOUTUC06 IC9300 E6 VSS IC9300 W21 VDD33 IC9300 E18 VSS IC9300 B5 RI5 IC9300 V6 AVSS_3 IC9300 J3 MONOUT0 IC9300 J2 MONOUT1 IC9300 AA4 VREF IC9300 V1 DQS0 IC9300 V2 DQ3 IC9300 K4 HDI IC9300 L22 DOUTDB11 IC9300 Y5 NCAS IC9300 C7 RI0 IC9300 D1 GI6 IC9300 C20 VSS IC9300 T3 AVDD25_1 IC9300 C11 DOUTUB15 IC9300 F19 DOUTUA01 IC9300 B6 RI1 IC9300 N10 VSS IC9300 E9 VDD33 IC9300 AB14 DQ8 L8L3.3V IC9300 K5 VDD33 IC9300 D19 VSS IC9300 E11 VDD33 IC9300 N14 VSS IC9300 W19 VSS IC9300 A8 TCKSEL0 IC9300 E10 VDD33 IC9300 N4 TMS IC9300 L14 VSS IC9300 P22 DOUTDB08 IC9300 AA2 VSS IC9300 D13 DOUTUC12 IC9300 B9 FPCLK J0HABH000013 FL9306 IC9300 M11 VSS IC9300 D5 GI2 IC9300 C21 DOUTUA02 IC9300 F3 GI9 IC9300 AB1 VSS IC9300 T22 DOUTDC06 IC9300 AB16 AVDD33_2 IC9300 AA22 VSS IC9300 J18 VDD33 IC9300 C15 DOUTUB09 C9319 0.1u 16V IC9300 V5 VSS R9391 10k IC9300 H4 BI7 IC9300 AB7 A6 IC9300 D8 OCK IC9300 E5 VSS IC9300 B19 DOUTUA04 IC9300 V14 VDD12 IC9300 K13 VSS IC9300 A22 VSS IC9300 T18 VDD33 IC9300 Y1 DQ0 IC9300 W16 SDIV1 IC9300 AB10 DQ29 R9580 1k IC9300 AB4 BA0 IC9300 Y8 A1 IC9300 C5 RI9 IC9300 J20 DOUTDC15 IC9300 C16 DOUTUC08 IC9300 AB17 VSS IC9300 AB2 VSS IC9300 U3 DQ6 IC9300 B22 VSS IC9300 AA21 VSS C9302 0.1u 16V IC9300 L4 TIIC IC9300 Y7 A0 IC9300 R3 DQ17 IC9300 A14 DOUTUA11 IC9300 R21 DOUTDA06 IC9300 E4 VDD12 IC9300 L21 DOUTDA11 IC9300 A15 DOUTUA10 IC9300 N12 VSS IC9300 AB12 DQS1 IC9300 W4 VSS IC9300 D20 DOUTUB03 FL9304 F1J1E1040022 1 2 3 C9303 0.1u 16V IC9300 E17 VSS L8L3.3V IC9300 M12 VSS IC9300 AB20 DOUTDB01 IC9300 AA9 A8 IC9300 C18 DOUTUB05 IC9300 F22 DRVCLKD3 IC9300 Y17 VSS IC9300 D11 DOUTUA15 IC9300 V12 VDD25 IC9300 W10 DQ27 IC9300 J19 DOUTDA15 IC9300 AB3 NCK IC9300 C3 VSS IC9300 C6 RI4 IC9300 L3 ID1 IC9300 L5 VDD33 IC9300 A4 RI6 IC9300 L2 ID0 IC9300 AB5 BA1 R9390 10k IC9300 K1 DCK IC9300 P20 DOUTDA07 IC9300 R4 DQ16 IC9300 M18 VDD12 IC9300 L20 DOUTDC12 IC9300 W6 NWE IC9300 Y19 VSS IC9300 B15 DOUTUB10 C9358 0.1u 16V IC9300 E7 VDD12 IC9300 AA3 CK IC9300 B4 RI8 IC9300 L19 DOUTDB12 IC9300 D16 DOUTUC07 from FPGA1 IIC from FPGA to DDR rromdata[00] rromdata[01] rromdata[02] rromdata[03] rromdata[04] rromdata[07] rromdata[10] rromdata[13] rromdata[05] rromdata[08] rromdata[11] rromdata[14] rromdata[06] rromdata[09] rromdata[12] rromdata[15] rromadrs[00] rromadrs[01] rromadrs[04] rromadrs[07] rromadrs[10] rromadrs[13] rromadrs[16] rromadrs[19] rromadrs[03] rromadrs[06] rromadrs[09] rromadrs[12] rromadrs[15] rromadrs[18] rromadrs[02] rromadrs[05] rromadrs[08] rromadrs[11] rromadrs[14] rromadrs[17] rromadrs[20] 57 60 63 55 58 59 61 62 56 DATA DRIVER PLASMA AI MN84521-A(LSI58) SUB FIELD PROCESSOR IC9300 RGB PROCESSOR FORMAT CONVERTER LEFT 84 83 81 82 91 MN84521 Left D-BOARD TNPA3820AJ(7/8) TH-42PV65C D-Board (7 of 8) Schematic Diagram TH-42PV65C D-Board (7 of 8) Schematic Diagram 104 14.43.D 电路板 （8/8）线路图 + L8DL_DQS3 L8L_SDCKE L8DL_A3 L8L_DQ28 L8DL_CLK L8DL_A9 L8DL_NCAS L8DL_DQ22 L8DL_DQ25 L8DL_NRAS L8DL_DQ26 L8DL_DQ31 L8DL_A1 L8L_DQ12 L8DL_NWE L8DL_DQ24 L8DL_DQ7 L8DL_DQ11 L8DL_DQ4 L8DL_DQ0 L8DL_NCAS L8L_DQS1 L8DL_CKE L8DL_DQ11 L8DL_DQ9 L8L_DQ17 L8L_A10 L8L_DQ25 L8L_DQS0 L8DL_DQ23 L8DL_A3 L8L_DQ10 L8DL_DQ21 L8L_CS L8L_DQ16 L8DL_DQS0 L8DL_DQ2 L8L_DQ24 L8DL_A4 L8DL_DQ9 L8L_DQ22 L8L_A3 L8DL_DQ13 L8L_DQ20 L8L_DQ4 L8DL_NCLK L8L_SDCLKO L8L_BA0 L8DL_DQS3 L8L_DQ27 L8L_DQ19 L8L_NSDCLKO L8DL_DQS2 L8DL_DQ1 L8L_DQ3 L8L_DQ0 L8DL_DQ29 L8DL_DQ19 L8L_A2 L8L_DQ18 L8DL_DQ6 L8L_DQ9 L8DL_NCS L8DL_DQ28 L8DL_A7 L8DL_DQS1 L8DL_A10 L8DL_A6 L8L_DQS3 L8DL_DQ14 L8DL_DQ0 L8DL_DQ8 L8DL_DQ19 L8L_DQ5 L8DL_DQ30 L8DL_DQ15 L8DL_A8 L8DL_DQ30 L8DL_DQ5 L8DL_DQ8 L8L_A8 L8DL_DQ5 L8DL_DQ27 L8L_DQ23 L8DL_DQ24 L8L_BA1 L8DL_DQ14 L8DL_A1 L8DL_DQ12 L8DL_DQ10 L8DL_DQS1 L8DL_DQ10 L8DL_DQ13 L8DL_A5 L8DL_NCS L8DL_DQ4 L8L_CAS L8DL_A9 L8DL_A2 L8DL_DQ29 L8DL_DQ16 L8DL_BA1 L8DL_BA1 L8DL_DQ1 L8L_DQ6 L8DL_DQ22 L8DL_CKE L8L_A7 L8DL_DQS0 2.5V L8DL_A10 L8L_DQ30 L8L_A9 L8DL_A0 L8DL_DQ25 L8L_DQ2 L8DL_BA0 L8DL_DQS2 L8L_DQ21 L8DL_DQ20 L8DL_DQ23 L8DL_DQ27 L8L_A4 L8L_DQ29 L8DL_DQ16 L8L_WE L8DL_DQ26 L8L_A6 L8DL_DQ21 L8L_DQ15 L8DL_DQ3 L8DL_DQ15 L8DL_A0 L8DL_A4 L8L_DQ8 L8DL_NRAS L8DL_DQ3 L8DL_DQ31 L8L_A11 L8DL_DQ7 L8DL_A11 L8DL_A11 L8L_DQ7 L8L_DQ1 L8L_DQS2 L8DL_DQ28 L8DL_DQ12 L8L_DQ13 L8L_A5 L8DL_A8 L8L_DQ26 L8DL_BA0 L8L_A0 L8DL_A6 L8DL_A2 L8L_DQ31 L8DL_DQ6 L8DL_DQ18 L8L_DQ11 L8DL_DQ18 L8L_DQ14 L8DL_DQ2 L8DL_NWE L8DL_A5 L8DL_DQ17 L8DL_DQ17 L8L_RAS L8L_A1 L8DL_DQ20 L8DL_A7 L8DL_CLK L8DL_NCLK IC9301 A7 DQ31 IC9301 E3 VDDQ IC9301 F3 VDDQ R9597 47 R9373 33 IC9301 M8 A6 IC9301 C10 VSSQ IC9301 A10 VSSQ IC9301 J7 VSS IC9301 L5 A2 IC9301 F12 DQ12 IC9301 K12 NC C9336 16V 0.1u IC9301 E5 VSS_Thermal IC9301 F10 VDDQ R9595 EXB38V470JV IC9301 J2 DQ23 IC9301 E9 VSSQ IC9301 G5 VSS_Thermal IC9301 J4 VSSQ IC9301 M6 A3 IC9301 C2 DQ5 IC9301 J1 DQ22 IC9301 B11 VDDQ IC9301 D3 VDD IC9301 G9 VSSQ IC9301 F6 VSS_Thermal C9346 16V 0.1u R9585 47 IC9301 M3 BA0 C9339 16V 0.1u C9332 16V 0.1u IC9301 K4 VSS IC9301 F8 VSS_Thermal IC9301 A6 DQ0 IC9301 D8 VSSQ IC9301 L11 CK IC9301 G11 DM1 IC9301 F9 VSSQ IC9301 E10 VDDQ IC9301 B4 VDDQ IC9301 A4 DQ3 C9348 16V 0.1u IC9301 C12 DQ25 C9329 16V 0.1u IC9301 E8 VSS_Thermal IC9301 K8 RFU1 C9352 56u 4V IC9301 A11 DM3 C9342 16V 0.1u C9334 16V 0.1u IC9301 J10 VDDQ IC9301 E11 DQ15 L8L2.5V IC9301 J6 VSS IC9301 B2 VDDQ R9582 1k C9338 16V 0.1u IC9301 B7 VDDQ IC9301 G12 DQS1 IC9301 L10 CK C9350 16V 0.1u IC9301 K10 VDD R9592 EXB38V470JV IC9301 M2 NC IC9301 H11 DQ11 IC9301 M7 A4 C9331 16V 0.1u IC9301 D9 VSS IC9301 D10 VDD IC9301 H5 VSS_Thermal IC9301 L7 A9 IC9301 J12 DQ8 IC9301 A5 DQ2 IC9301 L1 RAS IC9301 D11 VDDQ IC9301 E7 VSS_Thermal IC9301 K2 WE IC9301 B8 DQ30 IC9301 H9 VSSQ IC9301 C11 DQ26 R9375 150 IC9301 B12 DQ27 IC9301 E4 VSSQ IC9301 A9 DQ28 R9593 EXB38V470JV IC9301 F4 VSSQ IC9301 M10 A8/AP C9335 16V 0.1u R9591 EXB38V470JV IC9301 D6 VSS C9347 16V 0.1u IC9301 C9 VSSQ IC9301 C7 VDD R9372 47 IC9301 H3 VDDQ IC9301 D1 DQ7 IC9301 B9 VDDQ C9327 16V 0.1u IC9301 G7 VSS_Thermal IC9301 B6 VDDQ IC9301 B3 NC IC9301 L9 RFU2 IC9301 G8 VSS_Thermal IC9301 D5 VSSQ IC9301 L8 A5 IC9301 E1 DQ17 IC9301 F7 VSS_Thermal IC9301 F11 DQ13 IC9301 M11 CKE IC9301 E2 DQ16 C9328 16V 0.1u R9374 EXB38V470JV IC9301 C6 VDD R9583 1k C9351 16V 0.1u IC9301 C5 VSSQ IC9301 K7 VDD C9330 16V 0.1u IC9301 H10 VDDQ IC9301 G6 VSS_Thermal R9590 EXB38V470JV R9594 EXB38V470JV IC9301 B5 DQ1 IC9301 K11 NC IC9301 E6 VSS_Thermal IC9301 B10 NC IC9301 H2 DQ20 IC9301 D12 DQ24 IC9301 L2 NC IC9301 D2 VDDQ R9371 EXB2HV470JV IC9301 F1 DQ19 IC9301 B1 DQ4 IC9301 K9 VSS IC9301 C4 VSSQ C9345 16V 0.1u IC9301 A8 DQ29 IC9301 L12 MCL IC9301 G3 NC IC9301 J3 VDDQ C9341 16V 0.1u IC9301 C8 VSSQ IC9301 J11 DQ9 R9588 EXB38V470JV R9584 33 IC9301 M9 A7 L8L2.5V C9344 16V 0.1u IC9301 L4 BA1 IC9301 M1 CS IC9301 K3 VDD IC9301 G4 VSSQ IC9301 F5 VSS_Thermal IC9301 G1 DQS2 IC9301 A2 DM0 IC9301 C3ABQJ000051 A1 DQS0 R9587 EXB38V470JV C9349 16V 0.1u IC9301 C1 DQ6 R9599 47 IC9301 D4 VSS C9343 16V 0.1u IC9301 H7 VSS_Thermal IC9301 L6 A11 IC9301 D7 VSS IC9301 G10 NC IC9301 K5 A10 IC9301 A12 DQS3 IC9301 H4 VSSQ IC9301 F2 DQ18 L8L2.5V IC9301 K1 CAS IC9301 J5 VSS IC9301 E12 DQ14 R9586 47 IC9301 M4 A0 IC9301 L3 NC IC9301 H1 DQ21 IC9301 H8 VSS_Thermal IC9301 G2 DM2 IC9301 C3 VSSQ C9340 16V 0.1u C9337 16V 0.1u IC9301 J9 VSSQ IC9301 M5 A1 C9333 16V 0.1u R9598 47 IC9301 H12 DQ10 R9596 47 IC9301 J8 VSS IC9301 A3 VSSQ IC9301 M12 VREF IC9301 H6 VSS_Thermal IC9301 K6 VDD R9589 EXB38V470JV DDR-Terminate DDR-SDRAM L 72 65 66 68 69 71 70 64 67 DDR SDRAM_L(128M) IC9301 91 D-BOARD TNPA3820AJ(8/8) TH-42PV65C D-Board (8 of 8) Schematic Diagram TH-42PV65C D-Board (8 of 8) Schematic Diagram 105 14.44.C1 电路板方框图 CLK2 CLK1 CLK0 CLK3 CLK2 CLK1 CLK0 CLK3 ODED CLRD PCD2 ODED CLRD PCD2 DOUTDC08 DOUTDC23 LED CLK1N-L R7188 VCC 2bit 4bit 6bit 6bit 6bit 8bit B18, C18 VCC C12 CB4 VCC A20-C21 A18,A19-C19 A12,A13-C13 AR11,BR11 AL10-CL11 A17,B17 A14-B15 10 80 IC7103 BUFFER CB1 CB2 IC7104 4bit BUFFER 8bit IC7105 BUFFER IC7102 CLK BUFFER A16-C16,C17 2bit 6bit 4bit Vda DDAL9 DDCL8 C11 6bit 2bit 48bit VCC DA8-DC23 DATA To D34 CB3 A8-C9 2bit B12,C12 4bit 2bit 6bit 6bit AR10-CR10,CR11 50 33 55 34 56 13-35,46-52,58-77 LED CLK1N-L 1 6 12 29 4 1 IC7101 VCC BUFFER 5V 5V 5VDET 6bit 6bit 6bit 6bit 6bit 6bit DATA DRIVE LOWER RIGHT(FRONT VIEW) C1 PANEL DATA DRIVER 55 34 56 8bit 8bit 8bit CB5 6bit 6bit CB6 6bit 6bit TH-42PV65C C1-Board Block Diagram TH-42PV65C C1-Board Block Diagram VCC IC7106 BUFFER VCC IC7107 BUFFER VCC IC7108 BUFFER To C22 106 14.45.C1 电路板 （1/4）线路图 2 3 D B 4 F 5 E 6 1 8 7 A C 9 C1-BOARD TNPA4219 (1/4) TH-42PV65C C1-Board (1 of 4) Schematic Diagram TH-42PV65C C1-Board (1 of 4) Schematic Diagram 1 2 3 4 5 6 7 8 CB1 CB2 107 14.46.C1 电路板 （2/4）线路图 11 12 13 14 15 10 17 16 18 C1-BOARD TNPA4219 (2/4) TH-42PV65C C1-Board (2 of 4) Schematic Diagram TH-42PV65C C1-Board (2 of 4) Schematic Diagram 1 2 3 4 5 6 7 8 AB_PCR_A 11 12 13 14 15 16 17 18 19 20 21 22 CB4 CB3 108 14.47.C1 电路板 （3/4）线路图 20 21 22 23 24 19 26 25 27 C1-BOARD TNPA4219 (3/4) TH-42PV65C C1-Board (3 of 4) Schematic Diagram TH-42PV65C C1-Board (3 of 4) Schematic Diagram 11 12 13 14 15 16 17 18 19 20 21 22 31 32 33 CB5 CB6 109 14.48.C1 电路板 （4/4）线路图 29 30 31 32 33 28 35 34 36 C1-BOARD TNPA4219 (4/4) TH-42PV65C C1-Board (4 of 4) Schematic Diagram TH-42PV65C C1-Board (4 of 4) Schematic Diagram 31 32 33 C12 To D34 To C22 110 14.49.C2 电路板方框图 LEL USL UEH UMH UML USH DRV_SOS8 CLK0P UEL CLK1N LEL CLK1N CLRL PCL R7262 30 1 32 VCC 5 18 8 20 1 19 21 29 B6,C6 2 4 6 VCC 31 7 6bit 34 60 C23 8bit 2bit 6bit 8bit 24 11 3 2bit 4bit A8-C9 6bit CB11 C21 IC7204 BUFFER IC7205 BUFFER BUFFER IC7206 CLK BUFFER IC7201 CB9 17 CB8 DATA 24bit DA0-DC7 VCC VCC 22 CB10 C22 30 23 12 2 IC7202 VCC BUFFER 65 68 27 26 5V 5VDET 5V UEH UML UEL USH USL DRV_SOS8 UMH DOUTDC7 DOUTDA0 12 6bit 6bit 6bit 6bit 6bit 6bit 6bit 6bit UEL USH USL UML UMH UEH DRV_SOS8 5V Vda Vda C2 DATA DRIVE LOWER LEFT (FRONT VIEW) PANEL DATA DRIVER TO D33 TO SS23 6bit 6bit CLKI0P ODEL CB7 TH-42PV65C C2-Board Block Diagram TH-42PV65C C2-Board Block Diagram VCC IC7203 BUFFER A6,A7-C7 4bit A4-C4,C5 6bit A2-C3 6bit A0-C1 A5,B5 2bit CLRL ODEL PCL LEL CLK1N CLK0P CLRL ODEL PCL DDCL8 Vda DDAL9 TO C12 111 14.50.C2 电路板 （1/3）线路图 2 3 D B 4 F 5 E 6 1 8 7 A C 9 C2-BOARD TNPA4220 (1/3) TH-42PV65C C2-Board (1 of 3) Schematic Diagram TH-42PV65C C2-Board (1 of 3) Schematic Diagram 1 2 3 4 5 6 7 8 9 To D33 To C12 C22 C21 CB7 112 14.51.C2 电路板 （2/3）线路图 11 12 13 14 15 10 17 16 18 C2-BOARD TNPA4220 (2/3) TH-42PV65C C2-Board (2 of 3) Schematic Diagram TH-42PV65C C2-Board (2 of 3) Schematic Diagram 1 2 3 4 5 6 8 7 9 11 12 13 14 15 16 17 CB8 CB9 113 14.52.C2 电路板 （3/3）线路图 20 21 22 23 24 19 26 25 27 C2-BOARD TNPA4220 (3/3) TH-42PV65C C2-Board (3 of 3) Schematic Diagram TH-42PV65C C2-Board (3 of 3) Schematic Diagram 11 12 13 14 15 16 17 6.8 CB10 CB11 114 14.53.SC，SU 和 SD 电路板方框图 + + CLK FSIU SCSU CEL2 FCLD CEL2 CEL CLK CPH1 CEL FSID CPH1 SCSU SID PROD CL PROU SIU CL CPH2 SIU FCLKD FCLU SID CPH2 FCLKU D6620 D6806 D6804 R6838 D6583 Q6743 Q6742 T6602 TP15V VSET 15V 5V R6839 16V_F VSUS TPVSUS 16V_F D6862 VSET D6860 15V_F VSUS D6841 Q6824 R6837 D6872 15V D6760 15V D6585 D6825 D6859 D6421 D6480 D6826 SI B34 A6 13 Q6681 Q6804 CML Q6401-Q6403 2 CL CLK 96 BUFFER B40 IC6951 VCC Q6691 GND Q6762 GND A11 Q6531,Q6532 BUFFER VCC C39 HO 64bit C34 CLK SO 5 SD4 LO A47 PRO 1 CL (Vscn) Vf OUTFET SCAN 9 VDD Q6644,Q6645 CL 32 IC6521 64 7 IC6901 Q6601,Q6602 PROU VDD IC6904 VDDH ENERGY RECOVERY AVR A40 8 VDD DRIVER 64bit VCC 32 PRO BUFFER CLK (SC3) VSUS AVR 3 20 GND IC6955 A33 S/P HIN 64bit +5V 3 SU SCAN OUT (UPPER) GND C76 GND VDD POWER OSC GND VDDH PRO CLK Vsus IC6903 LO GND FET SO (Vf+5V) +5V(SC3) GND TO P2 B31 IC6751 (+260V) CL SU3 2 Vad( 105V) VDD 1 CLK B2 PROD FCLD A46 IN 2 C10 18 +15V A7 CMH IC6724 8 +5V PC6702 Vfo C35 CLK AVR PRO COUPLER 64bit SID VDD 4 A30 VSETSOS DET PHOTO SD3 64 11 VSCN SUPERIMEPOSED 2 GND CSL (LOWER) 9 IC6953 IC6802 45 A32 A33 Adj. C36 VDD FCLKD 2 SI A45 VSCN Gen. A71 TPSC1 SIGNAL WAVE Q6551,Q6552 CLK VDDH B1 HIN SO IC6841 Vf IC6561,6562 CLK Q6841,Q6842 PRO SI S/P VDD COM Q6821,Q6822 C11 SC2 B8 Vf+5V 96 VDDH 32 VIN 64bit SO Vf+5V B36 VOUT GND (Vad 105V) A40 (UPPER) A8 64 IC6791 A8 PC6861 Vscn PRO C9 GND S/P VDDH SC A35 VDD PRO Vscn SC41 B8 7 PC6480 SI DRIVEB 20 COUPLER (SC3) 64bit 96 IC6954 PC6703 PHOTO PRO 3 CLK SU41 Q6802 Vscn GND C1 CMH A2 64 SO Vf (+140V) IC6752 IC6821 +5V(SC3) C79 CML 64bit OUTFET VSET SEPARATE IC6753 CSH S/P CL Q6616,Q6617 L6401 CLK CPH 6 SI Vsus CSL Q6641,Q6642 7 Vf+5V L6403 (SC2) Vf+5V IN B32 TPSCI CL Vfo SCAN PANEL A8 GND CL L6413 CL A36 SC SCAN DRIVE R6833 B35 GND LINE VDD 64bit L6411 SU4 C75 VCC R6834 1 FCLU A34 Vfo 23 GND A39 IC6681 Q6661-Q6663 Vf LINE R6835 SI FSID GND A31 Vf Q6671,Q6672 B11 IC6725 R6836 IC6905 VCC S/P IC6501 46 12 COMPARATOR 3 B9 VSET GND VDD VDDH SD42 PRO 32 ELECTRODES IC6871 (SC1) TO P23 IC6906 TPVSCN IC6671 IC6721 HO DRIVER PROU 9 SCSU TPVAD C8 5 Q6801 LINE PRO 384LINE SIU 2 1 VDD SI SC IC6956 VCC 7 VSET VDDH 8 PC6760 C50 5 A48 A32 Vf SO VDDH 3 Q6421-Q6423 A2 8 C74 PANEL Vf SO LINE SD2 FET +5V CL VDDH IC6581 VDD VAD SLOPE Vfo CSH 64 IC6601 B30 C51 VAD CONST Q6511,Q6512 A6 A5 SO VR6600 A73 ELECTRODES SU2 (Vfo) LINE SD1 PROD Q6803 LED(G) CLK 32 96 (+8V) 32 S/P A1 TPVSET VSET Gen. 1 Vf B33 IC6801 SO GND FSIU GND SC_SOS7 CEL VAD Gen.( 105V ) 384LINE Q6680 VDDH SID DRIVER SIU CL A33 VSET2 Gen. FET SO C41 IN 46 VDD CL A72 64bit +5V(SC2) 64bit IC6902 96 B7 CL VCC FCLKD A7 PHOTO BUFFER GND 64 VSET2 VAD C33 COUPLER FCLD VDDH S/P A30 Vsus Gen. A5 HO Vscn(VAD+140V) PRO B6 PC6801 VSET SLOPE Q6581 1 SC IC6771 IC6861 S/P 64bit DRIVER SC 1 32 SU1 COMPAR- FET LINE Vf+5V LO 2 B39 +15V FET Q6451,Q6452 IC6722 +5V 64 Vf+5V FCLKU 1 9 OUTFET 8 IC6773 SI DC/DC CONV. S/P 1 VDD Vscn IN FSID COUPLER OUTFET IC6774 LIN PC6701 3 PHOTO Vad 105V Q6441,Q6442 DRIVER SC30 COUPLER LINE P+5V SU CL +5V(SC3) SO HO 4 CLK RATOR A80 96 VSCN S/P PHOTO PC6871 FACTORY 32 RATOR FSIU COUPLER 3 Vf+5V USE COMPAR- SC42 COUPLER CEL2 B33 45 A31 1 16V_F VCC PHOTO 3 GND PC6705 FOR 96 19 IC6682 PHOTO LIN LO 17 64 9 B10 B5 FCLU +5V(SC1) PHOTO C73 5 FET LO 64bit COUPLER 1 A9 Q6647,Q6648 SI COUPLER VCC SC_SOS6 7 BUFFER PHOTO AVR 8 SO LINE IC6952 SD GND COUPLER A10 3 A70 C48 VDDH S/P PHOTO CEL2 CLK 1 CLK PC6704 C49 Vf+5V Q6682 96 TO D20 VCC S/P SI CL FCLKU A42 PRO TPSOS6 TPSOS7 D6623,D6624 OUT FET FET OUT FET OUT FET OUT FET OUT FET OUT VCC FET HO GND FET VAD SEPARATE IN DRIVER OUT Q6781 IC6772 LO Q6782 D6904 D6953 D6903 D6954 Q6621 Q6622,D6621 IC6610 RATOR COMPAR- 15Vf SD SCAN OUT (LOWER) FLOATING GND COLD ENERGY RECOVERY SOS DET LED BLINKING : 6 TIMES SC FLOATING PART SOS DET LED BLINKING : 7 TIMES FLOATING GND COLD TH-42PV65C SC, SU and SD-Board Block Diagram TH-42PV65C SC, SU and SD-Board Block Diagram 115 14.54.SC 电路板 （1/2）线路图 + + + + + + + + AA_CLK AA_SIU AA_SID AA_SCSU AA_CL AA_CEL CEL2 CPH CML CMH CSH CBK CEL CSL AA_CEL2 AC_CPH1 AC_CPH2 SOS6_SC1 100V SOS7_SC2 5V 0-305V 0-200V D6471 MA3DF30000LZ R6592 4.7k Q6422 B1JAEP000001 D6522 D1FL40 Q6517 2SA2071T100Q IC6871 C0BBBA000022 1 2 3 4 5 6 7 8 150 R6523 15V C6566 50V 0.01u R6866 2.2k C6565 50V 0.01u R6425 15 R6793 100 Q6441 B1JADN000002 PC6861 B3PBA0000223 1 2 3 4 TP23 R6564 EXB38V470JV R6475 4.7k R6531 10 1 2 3 TP52 R6791 1k R6875 3.3k D6451 D1FL40 L6484 G0ZZ00002183 C6563 10V 100u TP33 D6482 RF2001T3DFF55 D6524 B0ECHP000003 TP7 150 R6504 R6861 39k 1 R6508 R6585 1.2k C6414 220V 200u SOS7_SC2 C6593 50V 1000p TP9 D6431 B0HBSP000019 MAIN_STOP C6502 25V 4.7u 15V_F L6466 G0ZZ00002183 D6491 B0HBSP000019 R6877 3.9k R6581 10k D6441 B0ECHP000003 R6551 10 15V SC2 1 3 TP10 Q6512 2SA2071T100Q R6454 10 TP30 C6504 25V 4.7u L6411 L6488 G0ZZ00002183 Q6791 2SD0601A0L TP15 L6602 G0ZZ00002183 TP20 R6468 82k TP14 D6872 MA2J11100L C6521 25V 1u R6478 4.7k Q6401 B1JADN000001 G D S C6411 220V 200u TP25 R6876 1.2k R6584 10k 16V_F R6553 10k TP39 C6561 10V 100u R6563 EXB38V470JV TP17 C6581 25V 1u D6461 RF2001T3DFF55 16V_F R6863 47k R6865 2.2k R6872 39k D6501 B0ECHP000003 15V R6503 10 R6562 EXB38V470JV R6522 100 C6524 25V 4.7u 150 R6505 R6867 3.9k 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 L6412 L6468 G0ZZ00002183 R6511 10k TP2 PC6871 B3PBA0000223 1 2 3 4 TP4 L6465 G0ZZ00002183 C6412 220V 200u Q6451 B1JADP000002 C6527 25V 4.7u R6467 82k C6872 25V 1u R6561 EXB38V470JV R6583 39k C6512 250V 4u R6451 10 L6487 G0ZZ00002183 C0JBAA000377 IC6472 1 IN_B 2 IN_A 3 GND 5 VCC 4 OUT_Y R6591 EXB38V472JV Q6442 B1JADN000002 150 R6524 IC6861 C0BBBA000022 1 2 3 4 5 6 7 8 R6452 10 TP12 C6480 50V 0.1u Q6421 B1JAEP000001 5V L6464 G0ZZ00002183 R6521 100 L6591 G0ZZ00002183 R6501 100 D6791 MAZ82000ML TP21 D6585 MA2J11100L C0JBAZ000005 IC6561 1G~ 1 2 1A1 3 2Y4 4 1A2 5 2Y3 6 1A3 7 2Y2 8 1A4 9 2Y1 10 GND 11 2A1 12 1Y4 13 2A2 14 1Y3 15 2A3 16 1Y2 17 2A4 18 1Y1 19 2G~ 20 VCC R6453 10 R6862 47k R6424 15 TP19 R6533 10k R6532 10k R6587 2.2k R6405 15 L6481 G0ZZ00002183 TP6 R6871 39k C6522 25V 4.7u R6479 100k R6552 10k L6485 G0ZZ00002183 SOS7_SC2 L6413 TP24 L6486 G0ZZ00002183 R6516 10k R6566 EXB38V472JV R6565 EXB38V472JV R6422 15 C6873 50V 0.01u R6582 39k Q6423 B1JAEP000001 D6862 MA2J11100L R6401 15 Q6551 B1ABRD000003 TP11 C6401 630V 5600p TP1 D6583 LNJ301MPUJA C0JBAZ000005 IC6562 1G~ 1 2 1A1 3 2Y4 4 1A2 5 2Y3 6 1A3 7 2Y2 8 1A4 9 2Y1 10 GND 11 2A1 12 1Y4 13 2A2 14 1Y3 15 2A3 16 1Y2 17 2A4 18 1Y1 19 2G~ 20 VCC R6590 220 L6601 G0ZZ00002183 C6431 250V 4u TP35 R6879 4.7k Q6471 B1CHGD000006 G D S 5V R6878 22k R6402 15 TP16 C6413 220V 200u R6526 0 R6506 10 L6482 G0ZZ00002183 Q6552 B1ADRD000001 TP38 Q6531 B1ABRD000003 C0ZBZ0000895 IC6501 1 LO 2 GND 3 VCC 4 NC 5 NC 6 VS 7 VB 8 HO 9 NC 10 NC 11 NC 12 HIN 13 NC 14 LIN 15 GND 16 NC D6521 D1FL40 SOS7_SC2 Q6516 2SC5824T100R D6480 MA2J11100L R6465 27k D6401 B0HBSN000008 R6441 10 R6502 100 R6443 10 Q6532 B1ADRD000001 D6523 D1FL40 R6442 10 R6568 EXB38V472JV R6864 9.1k VF_GND C6863 50V 0.01u C6592 25V 470u D6584 MAZ80510LL R6426 15 Q6403 B1JADN000001 C6505 25V 4.7u R6588 10k R6404 15 Q6452 B1JADP000002 Q6511 2SC5824T100R D6466 MA2J11100L TP18 R6792 10k L6463 G0ZZ00002183 D6861 MAZ80510LL L6592 G0ZZ00002183 R6586 1.8k 15V TP31 R6567 EXB38V472JV R6423 15 C6582 16V 1u VSUS C0ZBZ0001324 IC6521 1 LO 2 Vcom 3 VCC2 4 NC 5 NC 6 VS 7 VB 8 HO 9 NC 10 NC 11 VCC 12 HIN 13 NC 14 LIN 15 GND 16 NC D6871 MAZ80510LL R6869 4.7k B0ECHP000003 D6472 R6403 15 C6525 25V 4.7u TP26 R6512 10k D6581 MAZ83300ML R6466 56k TP27 5V D6462 RF2001T3DFF55 5V C6861 16V 1u 200u 220V C6415 R6525 0 Q6402 B1JADN000001 R6477 1k D6582 MAZ83300ML TP32 R6874 8.2k IC6581 C0BBBA000022 1 2 3 4 5 6 7 8 TP29 R6476 4.7k R6444 10 TP8 C6472 50V 0.1u R6517 10k TP5 TP22 R6406 15 C6871 16V 1u Q6581 2SD0601A0L D6502 B0ECHP000003 C6862 25V 1u L6462 G0ZZ00002183 TP34 D6432 B0HBSP000019 VSCN_F C6511 250V 4u MAIN_STOP 1 R6507 C6591 25V 1u 1 R6509 TP28 TP13 L6467 G0ZZ00002183 D6481 RF2001T3DFF55 R6873 39k L6461 G0ZZ00002183 L6483 G0ZZ00002183 R6421 15 R6868 22k VSUS C6402 2200p 630V D6402 B0HBSN000008 D6820 MA2J11100L D6821 MA2J11100L L6402 L6403 L6401 C6421 630V C6422 630V +15V GND (GREEN LED) + - + - TP15V +15V GND Vsus GND GND GND GND TPVSUS TPSOS7 TPSOS6 + + - - - - + + F E 1 5 6 8 7 3 4 C D B 9 A 2 BUFFER BUFFER FET DRIVER ENERGY RECOVERY COMPARATOR COMPARATOR COMPARATOR FET DRIVER Vsus Gen. SC 20 D-BOARD (D20) TO SC 23 P-BOARD (P23) TO TO (P2) P-BOARD SC-BOARD (1/2) TNPA3814AG 42inch:1.9u 42inch:1.9u 42inch:1.9u 42inch:1.9u 42inch:1.9u 42inch:1.9u 4 1 5 3 2 CLK SIU SCSU P5V CL SID FLOATING GND COLD NC 37inch:5600p 42inch:2700p 37inch:5600p 42inch:2700p 189.0 0 0 15.0 15.0 0 5.3 0 0 4.3 0 2.2 0.7 0.8 2.9 3.9 0 0.1 0.9 0 0 5.0 0 0 2.8 0.5 TH-42PV65C SC-Board (1 of 2) Schematic Diagram TH-42PV65C SC-Board (1 of 2) Schematic Diagram FLOATING GND COLD 116 14.55.SC 电路板 （2/2）线路图 REF K A + + + REF K A + + + REF K A + + REF K A + + + + + + AA_CEL -90V AB_FCLD AB_FCLU AC_CPH1 -80V AA_CEL2 AA_SID AA_SIU AA_CLK AA_CL AA_SCSU AB_FCLKU AB_FCLKD AB_PROD AB_PROU AB_FSID AB_FSIU 215V AC_CPH2 460V 460V 260-460V 15V 15V 460V 30V 30V AB_FSIU AB_FCLD -88V AB_FCLU AB_FCLKU AB_PROU AB_PROD AB_FCLKD AB_FSID 350V 460V -75V -90V 335V -105V 0V 330V 330V 460V +330V -105V +330V -105V C0JBAB000715 IC6602 1 NC 2 IN_A 3 GND 5 VCC 4 OUT_Y VSET C6702 50V 0.1u D6661 MA2J11100L R6815 18k C6662 630V 1000p TP46 R6757 100 ZA6401 K4CD01000011 R6760 1.2k TP57 R6648 10 VR6600 1k 1 2 3 R6807 3.3k Q6661 B1DEET000002 G D S R6755 100 TP56 D6732 MAZ80560HL D6730 MAZ80560HL ZA6402 K4CD01000011 R6674 5.6 C6704 50V 0.1u R6834 56k Q6671 B1DFET000001 G D S R6809 10k C6805 16V 1u IC6821 C0DBEMB00005 C6726 16V 1u 1 2 3 4 5 6 7 8 9 R6775 100 IC6751 C0CBADC00089 INPUT 3 2 COMMON OUTPUT 1 SOS7_SC2 R6762 10k R6716 2.2k D6825 MAZ8330 R6682 100 C6620 630V 2200p R6781 47 R6642 10 R6715 2.2k R6844 100 D6605 MAZ80510LL TP50 R6473 560 R6777 150 IC6725 C0CBADC00089 INPUT 3 2 COMMON OUTPUT 1 C6708 50V 0.1u C6725 25V 4.7u D6725 B0ECHP000003 D6806 B0ECHP000003 15V R6668 4.7k 5V R6658 100 Q6682 2SK389500L G D S IC6671 C0ZBZ0001325 1 Vcc 2 IN 3 GND 4 LO 5 NC 6 VS 7 HO 8 VB R6721 EXB38V680JV R6607 5.11k D6624 B0HDSM000005 R6745 4.7k TP41 C6754 35V 47u R6847 56k R6822 100k Q6842 2SC1473AEA D6684 MA2J11100L D6773 B0HCKS000002 R6717 2.2k C6822 350V 10u Q6762 2SA2071T100Q D6701 MAZ80560HL C6842 160V 100u TP40 SC42 A1 A2 A3 A4 A5 A6 A7 A8 A9 A10 A11 A12 A13 A14 A15 A16 A17 A18 A19 A20 A21 A22 A23 A24 A25 B1 B2 B3 B4 B5 B6 B7 B8 B9 B10 B11 B12 B13 B14 B15 B16 B17 B18 B19 B20 B21 B22 B23 B24 B25 B26 B27 B28 B29 B30 A26 A27 A28 A29 A30 B31 B32 B33 B34 A31 A32 A33 A34 A35 A36 A37 A38 A39 A40 B35 B36 B37 B38 B39 B40 R6839 4.7k C6661 630V 1000p D6760 MA2J11100L R6621 220 R6841 15k IC6801 C0DBEMB00005 R6743 1k D6662 MAZ83300ML C6771 16V 1u R6673 5.6 Q6804 2SD0601A0L C6721 50V 100u D6729 MAZ80560HL D6642 B0HCKS000002 TP60 D6826 MA111 C0DBEKA00003 IC6471 1 NC 2 A 3 K 5 A 4 REF R6662 3k R6603 100 SOS7_SC2 IC6601 C0ZBZ0001325 1 Vcc 2 IN 3 GND 4 LO 5 NC 6 VS 7 HO 8 VB R6812 240k D6721 B0HCKS000002 IC6772 C0ZBZ0001325 1 Vcc 2 IN 3 GND 4 LO 5 NC 6 VS 7 HO 8 VB R6660 220k R6827 0 R6756 100 R6711 2.2k R6667 4.7k IC6681 C0ZBZ0001325 1 Vcc 2 IN 3 GND 4 LO 5 NC 6 VS 7 HO 8 VB R6831 15k Q6680 B1ADNF000006 R6690 150 TP55 R6620 8.2 Q6601 B1DFES000003 G D S Q6841 2SD1263AP0LB D6801 M1FS4 TP54 R6604 150 D6683 MA2J11100L C6845 50V 0.01u VSET R6860 8.2 C6776 50V 0.1u R6801 0.22 D6860 B0HCKS000002 D6802 B0JCME000037 R6837 47k TP58 1 2 3 4 5 6 7 8 9 15V_F R6702 470 D6477 MA2J11100L R6802 0.22 R6613 1M VSUS PC6480 B3PBA0000223 1 2 3 4 C6701 50V 0.1u R6823 100k C6753 25V 4.7u R6713 2.2k C6804 250V 10u R6826 270k D6667 MA2J11100L R6744 10k D6601 MAZ8240 T6602 ETS25AZ139AD 1 S5 2 S4 4 S2 5 S1 7 P1 10 B1 9 B2 3 S3 6 P2 R6471 3.9k R6609 1k Q6742 2SD0601A0L PC6701 B3PBA0000233 1 2 3 4 5 6 7 8 TP64 C6602 25V 4.7u D6604 MA2J11100L C6706 50V 0.1u C6777 50V 0.1u SC41 A1 A2 A3 A4 A5 A6 A7 A8 A9 A10 A11 A12 A13 A14 A15 A16 A17 A18 A19 A20 A21 A22 A23 A24 A25 B1 B2 B3 B4 B5 B6 B7 B8 B9 B10 B11 B12 B13 B14 B15 B16 B17 B18 B19 B20 B21 B22 B23 B24 B25 B26 B27 B28 B29 B30 A26 A27 A28 A29 A30 B31 B32 B33 B34 A31 A32 A33 A34 A35 A36 A37 A38 A39 A40 B35 B36 B37 B38 B39 B40 R6661 100k TP63 C6703 50V 0.1u R6825 270k D6619 B0HCKS000002 C6604 350V 47u IC6841 C0DBEMB00005 R6806 10k R6659 220k R6816 5.36k R6707 470 Q6641 B1DFKM000001 R6852 2.49k TP62 D6727 MAZ80560HL R6703 470 D6643 MA2J11100L 5V IC6771 C0CBADC00089 INPUT 3 2 COMMON OUTPUT 1 IC6724 C0CBADC00089 INPUT 3 2 COMMON OUTPUT 1 R6888 220k R6611 1M Q6642 B1DFKM000001 C0JBAA000377 IC6773 1 IN_B 2 IN_A 3 GND 5 VCC 4 OUT_Y R6846 56k D6771 B0JCME000037 R6672 10k IC6721 C0JBAZ000994 1 1A 2 1Y 3 2A 4 2Y 5 3A 6 3Y 7 GND 8 4Y 9 4A 10 5Y 11 5A 12 6Y 13 6A 14 VCC R6782 10k D6665 MAZ80510LL R6813 10k D6842 MA2J11100L TP51 R6824 10k Q6782 2SA2071T100Q C6772 25V 4.7u R6718 2.2k VF_GND D6620 B0HCKS000002 C6802 25V 220u R6608 1k L6841 J0JJC0000011 D6728 MAZ80560HL C6603 630V 1000p D6723 B0JCME000037 TP59 R6704 470 D6682 B0HCMM000014 D6663 MAZ83300ML C0JBAB000715 IC6753 1 NC 2 IN_A 3 GND 5 VCC 4 OUT_Y R6742 10k R6853 100 SOS7_SC2 C6796 25V 220u L6472 G0ZZ00002183 D6726 MAZ80560HL D6733 MAZ80560HL R6808 56 VR6602 5k 1 2 3 C6775 25V 4.7u D6623 B0HDSM000005 R6811 51k IC6802 C0DBEMB00005 C6841 160V 100u C6681 25V 4.7u C6807 160V 100u R6612 47 Q6681 2SK389500L G D S R6724 100 1 2 3 4 5 6 7 8 D6752 M1FS4-5063 R6776 100 R6710 2.2k R6706 470 N0BF1FB00001 IC6791 1 GND 2 GND 3 N.C. 4 VIN 5 VIN 6 N.C. 9 COM 10 COM 11 VOUT 12 VOUT R6605 100k PC6703 B3PBA0000233 1 2 3 4 5 6 7 8 D6702 MAZ80560HL VSCN_F C6803 50V 0.1u D6724 B0JCME000037 Q6647 B1DFKM000001 R6665 47 5V Q6691 2SK062000L G D S R6666 100k L6473 G0ZZ00002183 R6610 100k R6671 47 C6752 16V 1u 16V_F D6822 MA2J11100L D6603 MAZ82400ML R6644 10 C6773 25V 4.7u C6724 25V 4.7u PC6705 B3PBA0000233 1 2 3 4 5 6 7 8 Q6824 2SD601A Q6822 2SC3063000RL TP44 R6821 220 R6701 470 Q6662 2SD0601A0L R6886 220k R6641 10 Q6644 B1DFKM000001 Q6648 B1DFKM000001 D6478 B0HCKS000002 B0HDSM000005 R6696 2.2 R6828 5.23k 15V D6664 MAZ83300ML L6802 J0JJC0000011 PC6760 B3PBA0000223 1 2 3 4 Q6803 2SD814ARL D6686 MA2J11100L TP48 C6811 50V 0.01u R6663 10k R6835 56k ZA6403 K4CD01000011 R6759 4.7k C6691 160V 100u C6682 25V 4.7u D6823 MA2J11100L Q6802 2SB0709ARL Q6744 2SK062000L G D S C6795 25V 220u R6687 2.2k R6606 0 Q6801 B1BAEJ000014 D6805 MA2J11100L C6707 50V 0.1u R6700 470 Q6621 B1DFKM000001 R6647 10 Q6781 2SC5824T100R R6761 10 D6602 B0ECHP000003 D6606 B0HCMM000014 TP61 R6850 68k C6723 25V 4.7u D6804 B0ECHP000003 VSCN_F C6728 50V 1000p R6691 10k Q6645 B1DFKM000001 D6761 MA2J11100L Q6602 2SD0601A0L D6671 MA2J11100L PC6801 B3PBA0000223 1 2 3 4 R6833 56k D6687 MA2J11100L R6887 220k TP47 R6842 43k C6683 50V 0.1u R6685 470 C6705 50V 0.1u C6791 25V 220u R6848 10k Q6821 2SD1263AP0LB IC6752 C0ZBZ0001325 1 Vcc 2 IN 3 GND 4 LO 5 NC 6 VS 7 HO 8 VB C6755 50V 0.1u C0JBAA000377 IC6774 1 IN_B 2 IN_A 3 GND 5 VCC 4 OUT_Y D6803 MA2J11100L R6836 68k 5V R6684 10 C0JBAZ000994 IC6722 1 1A 2 1Y 3 2A 4 2Y 5 3A 6 3Y 7 GND 8 4Y 9 4A 10 5Y 11 5A 12 6Y 13 6A 14 VCC VF_GND R6708 470 R6829 220k R6688 4.7k R6645 10 D6841 B0ECHP000003 D6859 B0ECHP000003 C6727 16V 1u D6641 B0HCKS000002 R6474 1k C6606 630V 1000p TP45 Q6743 2SD0601A0L R6830 220k TP49 D6666 MA2J11100L C6605 50V 0.1u R6810 51k TP43 D6734 MA2J11100L R6472 2.2k 5V PC6702 B3PBA0000233 1 2 3 4 5 6 7 8 Q6663 2SD21850RL TP42 C6641 0.22u 250V C6671 25V 4.7u D6731 MAZ80560HL C6812 25V 1u D6843 MA2J11100L R6714 2.2k R6814 5.6k PC6704 B3PBA0000234 1 2 3 4 5 R6849 68k D6758 B0ECHP000003 R6697 2.2 C6806 160V 100u R6705 470 D6497 MA111 R6851 4.22k C6823 50V 0.01u R6723 2.2k L6801 J0JJC0000011 R6664 2.2k R6722 EXB38V680JV Q6672 B1DFET000001 G D S R6689 10 TP53 C0JBAA000377 IC6682 1 IN_B 2 IN_A 3 GND 5 VCC 4 OUT_Y D6607 MA2J11100L R6758 100 R6817 2.7k R6712 2.2k 15V R6686 10k C6601 25V 4.7u R6683 150 R6622 220 Q6622 B1DFKM000001 D6644 B0HCKS000002 R6746 10k R6747 10k R6843 62k R6845 62k R6619 1.5k C6610 25V 1u R6614 24k D6610 MAZ81500ML D6612 MA2J11100L IC6610 C0BBBA000022 1 2 3 4 5 6 7 8 C6612 25V 1u 15V_F D6611 MA2J11100L R6617 1M D6613 MA2J11100L R6618 12k R6615 24k R6616 15k C6611 50V 0.01u D6614 MA2J11100L (D1FK70) VAD TPVAD TPVSCN INIT-F VSET TPVSET TPSC1 AB_FSIU AB_FCLU AB_FCLKU AB_PROU AB_FSID AB_FCLD AB_FCLKD Vset SOS DET INIT-F AB_PROD TPVSET2 18 15 10 11 12 16 17 14 13 BUFFER BUFFER FET DRIVER SUPERIMEPOSED VSCN VSET SEPARATE FET DRIVER FET DRIVER VSET SLOPE VAD CONST FET DRIVER FET DRIVER VAD SEPARATE +5V(SC1) +5V(SC2) +5V(SC3) +5V(SC3) (SU41) SU-BOARD TO (SD42) SD-BOARD TO +5V(SC1) VAD Gen. VSET2 Gen. VSCN Gen. DC/DC CONV. SU-BOARD TO (SU45) TO SD-BOARD (SD46) SC 46 SC 45 SC 30 TNPA3814AG SC-BOARD (2/2) 1 5 3 2 4 Vf(High Voltage Floting GND) Vfo(Vscn Out) Vf(High Voltage Floting GND) Vscn volatage) (Vscn Vf(High Voltage Floting GND) Vfo(Vscn Out) volatage) VF5V Vf(High Voltage Floting GND) VF5V FLOATING GND COLD POWER OSC FLOATING GND COLD FLOATING GND COLD - - + + COMPARATOR * * * * m TH-42PV65C SC-Board (2 of 2) Schematic Diagram TH-42PV65C SC-Board (2 of 2) Schematic Diagram D6621 117 14.56.SU 电路板 （1/2）线路图 TERM SIDE TERM SIDE AB_766 AB_765 AB_764 AB_763 AB_762 AB_761 AB_760 AB_759 AB_758 AB_757 AB_756 AB_755 AB_754 AB_753 AB_752 AB_751 AB_750 AB_749 AB_748 AB_747 AB_746 AB_745 AB_744 AB_742 AB_743 AB_741 AB_739 AB_740 AC_702 AC_701 AC_700 AC_699 AC_698 AC_697 AC_696 AC_695 AC_694 AC_693 AC_692 AC_691 AC_690 AC_689 AC_688 AC_687 AC_686 AC_685 AC_684 AC_683 AC_682 AC_681 AC_680 AC_678 AC_679 AC_677 AC_675 AC_676 AD_638 AD_637 AD_636 AD_635 AD_634 AD_633 AD_632 AD_631 AD_630 AD_629 AD_628 AD_627 AD_626 AD_625 AD_624 AD_623 AD_622 AD_621 AD_620 AD_619 AD_618 AD_617 AD_616 AD_614 AD_615 AD_613 AD_611 AD_612 AB_705 AB_707 AB_709 AB_711 AB_713 AB_715 AB_717 AB_719 AB_721 AB_723 AB_725 AB_727 AB_729 AB_731 AB_733 AB_735 AB_737 AB_739 AB_741 AB_743 AB_745 AB_747 AB_749 AB_751 AB_753 AB_755 AB_757 AB_759 AB_761 AB_763 AB_767 AB_765 AB_706 AB_708 AB_710 AB_712 AB_714 AB_716 AB_718 AB_720 AB_722 AB_724 AB_726 AB_728 AB_730 AB_732 AB_734 AB_736 AB_738 AB_740 AB_742 AB_744 AB_746 AB_748 AB_750 AB_752 AB_754 AB_756 AB_758 AB_760 AB_762 AB_764 AB_768 AB_766 AC_641 AC_643 AC_645 AC_647 AC_649 AC_651 AC_653 AC_655 AC_657 AC_659 AC_661 AC_663 AC_665 AC_667 AC_671 AC_669 AC_673 AC_675 AC_677 AC_679 AC_681 AC_683 AC_685 AC_687 AC_689 AC_691 AC_693 AC_695 AC_697 AC_699 AC_703 AC_701 AC_642 AC_644 AC_646 AC_648 AC_650 AC_652 AC_654 AC_656 AC_658 AC_660 AC_662 AC_664 AC_666 AC_668 AC_670 AC_674 AC_676 AC_678 AC_680 AC_682 AC_684 AC_686 AC_688 AC_690 AC_692 AC_694 AC_696 AC_698 AC_700 AC_704 AC_702 AD_577 AD_579 AD_581 AD_583 AD_585 AD_587 AD_589 AD_591 AD_593 AD_595 AD_597 AD_599 AD_601 AD_603 AD_605 AD_607 AD_609 AD_611 AD_613 AD_615 AD_617 AD_619 AD_621 AD_623 AD_625 AD_627 AD_629 AD_633 AD_631 AD_635 AD_637 AD_639 AD_578 AD_584 AD_586 AD_588 AD_590 AD_592 AD_594 AD_596 AD_598 AD_600 AD_602 AD_604 AD_606 AD_608 AD_610 AD_612 AD_614 AD_616 AD_618 AD_620 AD_622 AD_624 AD_626 AD_628 AD_630 AD_632 AD_634 AD_636 AD_640 AD_638 AB_768 AB_767 AC_703 AC_704 AD_639 AD_640 AD_582 AC_672 AB_705 AB_706 AB_707 AB_708 AB_709 AB_710 AB_711 AB_712 AB_713 AB_714 AB_715 AB_716 AB_717 AB_718 AB_719 AB_720 AB_721 AB_722 AB_723 AB_724 AB_725 AB_726 AB_727 AB_728 AB_729 AB_730 AB_731 AB_732 AB_733 AB_734 AB_735 AB_736 AB_738 AB_737 AC_641 AC_642 AC_643 AC_644 AC_645 AC_646 AC_647 AC_648 AC_649 AC_650 AC_651 AC_652 AC_653 AC_654 AC_655 AC_656 AC_657 AC_658 AC_659 AC_660 AC_661 AC_662 AC_663 AC_664 AC_665 AC_666 AC_667 AC_668 AC_669 AC_670 AC_671 AC_672 AC_674 AC_673 AD_577 AD_578 AD_579 AD_580 AD_581 AD_582 AD_583 AD_584 AD_585 AD_586 AD_587 AD_588 AD_589 AD_590 AD_591 AD_592 AD_593 AD_594 AD_595 AD_596 AD_597 AD_598 AD_599 AD_600 AD_602 AD_601 AD_603 AD_604 AD_605 AD_606 AD_607 AD_608 AD_610 AD_609 AA_SI AA_SO1 AA_SO2 AA_SO3 AA_CLK AA_CL AA_PRO AA_PRO AA_CL AA_CLK AA_CLK AA_CL AA_SI AA_CL AA_CLK AA_PRO AD_580 AA_PRO AA_SO2 AA_SO1 AN16072A-VT IC6901 1 OUT3 2 OUT4 3 OUT5 4 OUT6 5 OUT7 6 OUT8 7 OUT9 8 OUT10 9 OUT11 10 OUT12 11 OUT13 12 OUT14 13 OUT15 14 OUT16 15 OUT17 16 OUT18 17 OUT19 18 OUT20 19 OUT21 20 OUT22 21 OUT23 22 OUT24 23 OUT25 24 OUT26 25 OUT27 26 OUT28 27 OUT29 28 OUT30 29 OUT31 30 OUT32 31 N.C. 32 VDDH 33 VDDH 34 N.C. 35 GND 36 GND 37 GND 38 TEST 39 GND 40 GND 41 GND 42 N.C. 43 VDDH 44 VDDH 45 N.C. 46 OUT33 47 OUT34 48 OUT35 49 OUT36 50 OUT37 51 OUT38 52 OUT39 53 OUT40 54 OUT41 55 OUT42 56 OUT43 57 OUT44 58 OUT45 59 OUT46 60 OUT47 61 OUT48 62 OUT49 63 OUT50 64 OUT51 65 OUT52 66 OUT53 67 OUT54 68 OUT55 69 OUT56 70 OUT57 71 OUT58 72 OUT59 73 OUT60 74 OUT61 75 OUT62 76 OUT63 77 OUT64 78 N.C. 79 VDDH 80 VDDH 81 N.C. 82 GND 83 GND 84 DIR 85 SO 86 CLK 87 LAT 88 VDD 89 OC1 90 OC2 91 SI 92 CLR 93 GND 94 GND 95 N.C. 96 VDDH 97 VDDH 98 N.C. 99 OUT1 100 OUT2 R6904 22 R6934 10k R6933 10k R6932 10k C6902 16V 1u R6909 220 C6904 16V 1u SU1 B36 B20 B4 A36 A20 A4 B39 B23 B7 A39 A23 A7 B42 B26 B10 A42 A26 A10 B45 B29 B13 A45 A29 A13 B48 B32 B16 A48 A32 A16 B35 B19 B3 A35 A19 A3 B38 B22 B6 A38 A22 A6 B41 B25 B9 A41 A25 A9 B44 B28 B12 A44 A28 A12 B47 B31 B15 A47 A31 A15 B34 B18 B2 A34 A18 A1 B37 B21 B5 A37 A21 A5 B40 B24 B8 A40 A24 A2 A8 B43 B27 B11 A43 A27 A11 B46 B30 B14 A46 A30 A14 B33 B17 B1 A33 A17 SU2 B36 B20 B4 A36 A20 A4 B39 B23 B7 A39 A23 A7 B42 B26 B10 A42 A26 A10 B45 B29 B13 A45 A29 A13 B48 B32 B16 A48 A32 A16 B35 B19 B3 A35 A19 A3 B38 B22 B6 A38 A22 A6 B41 B25 B9 A41 A25 A9 B44 B28 B12 A44 A28 A12 B47 B31 B15 A47 A31 A15 B34 B18 B2 A34 A18 A1 B37 B21 B5 A37 A21 A5 B40 B24 B8 A40 A24 A2 A8 B43 B27 B11 A43 A27 A11 B46 B30 B14 A46 A30 A14 B33 B17 B1 A33 A17 C6931 50V 1000p AN16072A-VT IC6902 1 OUT3 2 OUT4 3 OUT5 4 OUT6 5 OUT7 6 OUT8 7 OUT9 8 OUT10 9 OUT11 10 OUT12 11 OUT13 12 OUT14 13 OUT15 14 OUT16 15 OUT17 16 OUT18 17 OUT19 18 OUT20 19 OUT21 20 OUT22 21 OUT23 22 OUT24 23 OUT25 24 OUT26 25 OUT27 26 OUT28 27 OUT29 28 OUT30 29 OUT31 30 OUT32 31 N.C. 32 VDDH 33 VDDH 34 N.C. 35 GND 36 GND 37 GND 38 TEST 39 GND 40 GND 41 GND 42 N.C. 43 VDDH 44 VDDH 45 N.C. 46 OUT33 47 OUT34 48 OUT35 49 OUT36 50 OUT37 51 OUT38 52 OUT39 53 OUT40 54 OUT41 55 OUT42 56 OUT43 57 OUT44 58 OUT45 59 OUT46 60 OUT47 61 OUT48 62 OUT49 63 OUT50 64 OUT51 65 OUT52 66 OUT53 67 OUT54 68 OUT55 69 OUT56 70 OUT57 71 OUT58 72 OUT59 73 OUT60 74 OUT61 75 OUT62 76 OUT63 77 OUT64 78 N.C. 79 VDDH 80 VDDH 81 N.C. 82 GND 83 GND 84 DIR 85 SO 86 CLK 87 LAT 88 VDD 89 OC1 90 OC2 91 SI 92 CLR 93 GND 94 GND 95 N.C. 96 VDDH 97 VDDH 98 N.C. 99 OUT1 100 OUT2 R6901 100 R6902 22 1 2 3 4 5 6 7 8 9 C6901 50V 1000p AN16072A-VT IC6903 1 OUT3 2 OUT4 3 OUT5 4 OUT6 5 OUT7 6 OUT8 7 OUT9 8 OUT10 9 OUT11 10 OUT12 11 OUT13 12 OUT14 13 OUT15 14 OUT16 15 OUT17 16 OUT18 17 OUT19 18 OUT20 19 OUT21 20 OUT22 21 OUT23 22 OUT24 23 OUT25 24 OUT26 25 OUT27 26 OUT28 27 OUT29 28 OUT30 29 OUT31 30 OUT32 31 N.C. 32 VDDH 33 VDDH 34 N.C. 35 GND 36 GND 37 GND 38 TEST 39 GND 40 GND 41 GND 42 N.C. 43 VDDH 44 VDDH 45 N.C. 46 OUT33 47 OUT34 48 OUT35 49 OUT36 50 OUT37 51 OUT38 52 OUT39 53 OUT40 54 OUT41 55 OUT42 56 OUT43 57 OUT44 58 OUT45 59 OUT46 60 OUT47 61 OUT48 62 OUT49 63 OUT50 64 OUT51 65 OUT52 66 OUT53 67 OUT54 68 OUT55 69 OUT56 70 OUT57 71 OUT58 72 OUT59 73 OUT60 74 OUT61 75 OUT62 76 OUT63 77 OUT64 78 N.C. 79 VDDH 80 VDDH 81 N.C. 82 GND 83 GND 84 DIR 85 SO 86 CLK 87 LAT 88 VDD 89 OC1 90 OC2 91 SI 92 CLR 93 GND 94 GND 95 N.C. 96 VDDH 97 VDDH 98 N.C. 99 OUT1 100 OUT2 R6931 10k R6905 220 R6903 22 C6906 16V 1u D6901 MAZ80560HL C6914 50V 220p C6915 50V 220p PRO FSI FCLK FCL 8 1 A 3 2 B D E C 7 4 5 6 FCL PRO FCLK FSI VF5V VF5V Vf5 Vfo PDP SCAN DRIVER S/P 64bit S/P PDP SCAN DRIVER 64bit PDP SCAN DRIVER S/P 64bit SU-BOARD TNPA3818 (1/2) SCAN ELECTRODES To 1st 96pins of To 2nd 96pins of SCAN ELECTRODES 4 1 5 3 2 6 UP Vf5 Vf SC-BOARD (SC45) 45 SU TO TH-42PV65C SU-Board (1 of 2) Schematic Diagram TH-42PV65C SU-Board (1 of 2) Schematic Diagram 118 14.57.SU 电路板 （2/2）线路图 TERM SIDE TERM SIDE AE_574 AE_573 AE_572 AE_571 AE_570 AE_569 AE_568 AE_567 AE_566 AE_565 AE_564 AE_563 AE_562 AE_561 AE_560 AE_559 AE_558 AE_557 AE_556 AE_555 AE_554 AE_553 AE_552 AE_550 AE_551 AE_549 AE_547 AE_548 AF_510 AF_509 AF_508 AF_507 AF_506 AF_505 AF_504 AF_503 AF_502 AF_501 AF_500 AF_499 AF_498 AF_497 AF_496 AF_495 AF_494 AF_493 AF_492 AF_491 AF_490 AF_489 AF_488 AF_486 AF_487 AF_485 AF_483 AF_484 AG_446 AG_445 AG_444 AG_443 AG_442 AG_441 AG_440 AG_439 AG_438 AG_437 AG_436 AG_435 AG_434 AG_433 AG_432 AG_431 AG_430 AG_429 AG_428 AG_427 AG_426 AG_425 AG_424 AG_422 AG_423 AG_421 AG_419 AG_420 AE_513 AE_515 AE_517 AE_519 AE_521 AE_523 AE_525 AE_527 AE_529 AE_531 AE_533 AE_535 AE_537 AE_539 AE_541 AE_543 AE_545 AE_547 AE_549 AE_551 AE_553 AE_555 AE_557 AE_559 AE_561 AE_563 AE_565 AE_567 AE_569 AE_571 AE_575 AE_573 AE_514 AE_516 AE_518 AE_520 AE_522 AE_524 AE_526 AE_528 AE_530 AE_532 AE_534 AE_536 AE_538 AE_540 AE_542 AE_544 AE_546 AE_548 AE_550 AE_552 AE_554 AE_556 AE_558 AE_560 AE_562 AE_564 AE_566 AE_568 AE_570 AE_572 AE_576 AE_574 AF_449 AF_451 AF_453 AF_455 AF_457 AF_459 AF_461 AF_463 AF_465 AF_467 AF_469 AF_471 AF_473 AF_475 AF_479 AF_477 AF_481 AF_483 AF_485 AF_487 AF_489 AF_491 AF_493 AF_495 AF_497 AF_499 AF_501 AF_503 AF_505 AF_507 AF_511 AF_509 AF_450 AF_452 AF_454 AF_456 AF_458 AF_460 AF_462 AF_464 AF_466 AF_468 AF_470 AF_472 AF_474 AF_476 AF_478 AF_482 AF_484 AF_486 AF_488 AF_490 AF_492 AF_494 AF_496 AF_498 AF_500 AF_502 AF_504 AF_506 AF_508 AF_512 AF_510 AG_385 AG_387 AG_389 AG_391 AG_393 AG_395 AG_397 AG_399 AG_401 AG_403 AG_405 AG_407 AG_409 AG_411 AG_413 AG_415 AG_417 AG_419 AG_421 AG_423 AG_425 AG_427 AG_429 AG_431 AG_433 AG_435 AG_437 AG_439 AG_441 AG_443 AG_445 AG_447 AG_386 AG_388 AG_390 AG_392 AG_394 AG_396 AG_398 AG_400 AG_402 AG_404 AG_406 AG_408 AG_410 AG_412 AG_414 AG_416 AG_418 AG_420 AG_422 AG_424 AG_426 AG_428 AG_430 AG_432 AG_434 AG_436 AG_438 AG_440 AG_442 AG_444 AG_448 AG_446 AE_576 AE_575 AF_511 AF_512 AG_448 AG_447 AF_480 AE_513 AE_514 AE_515 AE_516 AE_517 AE_518 AE_519 AE_520 AE_521 AE_522 AE_523 AE_524 AE_525 AE_526 AE_527 AE_528 AE_529 AE_530 AE_531 AE_532 AE_533 AE_534 AE_535 AE_536 AE_537 AE_538 AE_539 AE_540 AE_541 AE_542 AE_543 AE_544 AE_546 AE_545 AF_449 AF_450 AF_451 AF_452 AF_453 AF_454 AF_455 AF_456 AF_457 AF_458 AF_459 AF_460 AF_461 AF_462 AF_463 AF_464 AF_465 AF_466 AF_467 AF_468 AF_469 AF_470 AF_471 AF_472 AF_473 AF_474 AF_475 AF_476 AF_477 AF_478 AF_479 AF_480 AF_482 AF_481 AG_385 AG_386 AG_387 AG_388 AG_389 AG_390 AG_391 AG_392 AG_393 AG_394 AG_395 AG_396 AG_397 AG_398 AG_399 AG_400 AG_401 AG_402 AG_403 AG_404 AG_405 AG_406 AG_407 AG_408 AG_409 AG_410 AG_411 AG_412 AG_413 AG_414 AG_415 AG_416 AG_418 AG_417 AA_SO4 AA_SO5 AA_CLK AA_CL AA_PRO AA_CLK AA_CL AA_PRO AA_CLK AA_CL AA_PRO 140V(DC) 140V AA_SO4 AA_SO3 AA_SO5 C8 C43 C40 C32 C23 C34 C24 C64 C19 C37 C22 C76 C4 C6933 250V 1u C31 C53 C6910 16V 1u C78 C44 C16 C18 C38 C12 C7 C33 C63 R6913 220 C10 C15 R6924 220 C41 C9 C39 C61 C26 C5 C6 C52 C6932 250V 1u C73 C54 D6903 B0ECHP000003 C6935 250V 1u C36 C17 C55 C46 C77 C67 C14 SU4 B36 B20 B4 A36 A20 A4 B39 B23 B7 A39 A23 A7 B42 B26 B10 A42 A26 A10 B45 B29 B13 A45 A29 A13 B48 B32 B16 A48 A32 A16 B35 B19 B3 A35 A19 A3 B38 B22 B6 A38 A22 A6 B41 B25 B9 A41 A25 A9 B44 B28 B12 A44 A28 A12 B47 B31 B15 A47 A31 A15 B34 B18 B2 A34 A18 A1 B37 B21 B5 A37 A21 A5 B40 B24 B8 A40 A24 A2 A8 B43 B27 B11 A43 A27 A11 B46 B30 B14 A46 A30 A14 B33 B17 B1 A33 A17 C30 D6904 B0ECHP000003 R6935 220k C79 C57 C25 C6912 16V 1u AN16072A-VT IC6905 1 OUT3 2 OUT4 3 OUT5 4 OUT6 5 OUT7 6 OUT8 7 OUT9 8 OUT10 9 OUT11 10 OUT12 11 OUT13 12 OUT14 13 OUT15 14 OUT16 15 OUT17 16 OUT18 17 OUT19 18 OUT20 19 OUT21 20 OUT22 21 OUT23 22 OUT24 23 OUT25 24 OUT26 25 OUT27 26 OUT28 27 OUT29 28 OUT30 29 OUT31 30 OUT32 31 N.C. 32 VDDH 33 VDDH 34 N.C. 35 GND 36 GND 37 GND 38 TEST 39 GND 40 GND 41 GND 42 N.C. 43 VDDH 44 VDDH 45 N.C. 46 OUT33 47 OUT34 48 OUT35 49 OUT36 50 OUT37 51 OUT38 52 OUT39 53 OUT40 54 OUT41 55 OUT42 56 OUT43 57 OUT44 58 OUT45 59 OUT46 60 OUT47 61 OUT48 62 OUT49 63 OUT50 64 OUT51 65 OUT52 66 OUT53 67 OUT54 68 OUT55 69 OUT56 70 OUT57 71 OUT58 72 OUT59 73 OUT60 74 OUT61 75 OUT62 76 OUT63 77 OUT64 78 N.C. 79 VDDH 80 VDDH 81 N.C. 82 GND 83 GND 84 DIR 85 SO 86 CLK 87 LAT 88 VDD 89 OC1 90 OC2 91 SI 92 CLR 93 GND 94 GND 95 N.C. 96 VDDH 97 VDDH 98 N.C. 99 OUT1 100 OUT2 C49 C69 C58 C47 C80 C13 C42 C35 C70 SU3 B36 B20 B4 A36 A20 A4 B39 B23 B7 A39 A23 A7 B42 B26 B10 A42 A26 A10 B45 B29 B13 A45 A29 A13 B48 B32 B16 A48 A32 A16 B35 B19 B3 A35 A19 A3 B38 B22 B6 A38 A22 A6 B41 B25 B9 A41 A25 A9 B44 B28 B12 A44 A28 A12 B47 B31 B15 A47 A31 A15 B34 B18 B2 A34 A18 A1 B37 B21 B5 A37 A21 A5 B40 B24 B8 A40 A24 A2 A8 B43 B27 B11 A43 A27 A11 B46 B30 B14 A46 A30 A14 B33 B17 B1 A33 A17 C6908 16V 1u C62 C2 C75 C29 AN16072A-VT IC6906 1 OUT3 2 OUT4 3 OUT5 4 OUT6 5 OUT7 6 OUT8 7 OUT9 8 OUT10 9 OUT11 10 OUT12 11 OUT13 12 OUT14 13 OUT15 14 OUT16 15 OUT17 16 OUT18 17 OUT19 18 OUT20 19 OUT21 20 OUT22 21 OUT23 22 OUT24 23 OUT25 24 OUT26 25 OUT27 26 OUT28 27 OUT29 28 OUT30 29 OUT31 30 OUT32 31 N.C. 32 VDDH 33 VDDH 34 N.C. 35 GND 36 GND 37 GND 38 TEST 39 GND 40 GND 41 GND 42 N.C. 43 VDDH 44 VDDH 45 N.C. 46 OUT33 47 OUT34 48 OUT35 49 OUT36 50 OUT37 51 OUT38 52 OUT39 53 OUT40 54 OUT41 55 OUT42 56 OUT43 57 OUT44 58 OUT45 59 OUT46 60 OUT47 61 OUT48 62 OUT49 63 OUT50 64 OUT51 65 OUT52 66 OUT53 67 OUT54 68 OUT55 69 OUT56 70 OUT57 71 OUT58 72 OUT59 73 OUT60 74 OUT61 75 OUT62 76 OUT63 77 OUT64 78 N.C. 79 VDDH 80 VDDH 81 N.C. 82 GND 83 GND 84 DIR 85 SO 86 CLK 87 LAT 88 VDD 89 OC1 90 OC2 91 SI 92 CLR 93 GND 94 GND 95 N.C. 96 VDDH 97 VDDH 98 N.C. 99 OUT1 100 OUT2 C3 C59 C56 C48 C68 C28 C21 C20 C65 C6934 250V 1u C60 C50 C51 C45 C11 C72 C27 C66 C71 C74 C1 R6917 220 AN16072A-VT IC6904 1 OUT3 2 OUT4 3 OUT5 4 OUT6 5 OUT7 6 OUT8 7 OUT9 8 OUT10 9 OUT11 10 OUT12 11 OUT13 12 OUT14 13 OUT15 14 OUT16 15 OUT17 16 OUT18 17 OUT19 18 OUT20 19 OUT21 20 OUT22 21 OUT23 22 OUT24 23 OUT25 24 OUT26 25 OUT27 26 OUT28 27 OUT29 28 OUT30 29 OUT31 30 OUT32 31 N.C. 32 VDDH 33 VDDH 34 N.C. 35 GND 36 GND 37 GND 38 TEST 39 GND 40 GND 41 GND 42 N.C. 43 VDDH 44 VDDH 45 N.C. 46 OUT33 47 OUT34 48 OUT35 49 OUT36 50 OUT37 51 OUT38 52 OUT39 53 OUT40 54 OUT41 55 OUT42 56 OUT43 57 OUT44 58 OUT45 59 OUT46 60 OUT47 61 OUT48 62 OUT49 63 OUT50 64 OUT51 65 OUT52 66 OUT53 67 OUT54 68 OUT55 69 OUT56 70 OUT57 71 OUT58 72 OUT59 73 OUT60 74 OUT61 75 OUT62 76 OUT63 77 OUT64 78 N.C. 79 VDDH 80 VDDH 81 N.C. 82 GND 83 GND 84 DIR 85 SO 86 CLK 87 LAT 88 VDD 89 OC1 90 OC2 91 SI 92 CLR 93 GND 94 GND 95 N.C. 96 VDDH 97 VDDH 98 N.C. 99 OUT1 100 OUT2 D6902 MAZ80560HL R6936 220k C6916 50V 220p C6917 50V 220p C6918 50V 220p Vscn Vf Vfo Vf VF5V VF5V 15 11 10 13 8 14 12 9 FOIL SIDE (UPPER) COMPONENT SIDE (LOWER) Vfo(Vscn Out) (Vscn volatage) SU41(Card Edge 80Pin) Vf(High Voltage Floting GND) Vf(High Voltage Floting GND) Vf5 Vscn 64bit PDP SCAN DRIVER S/P PDP SCAN DRIVER S/P 64bit PDP SCAN DRIVER S/P 64bit SU-BOARD TNPA3818 (2/2) SCAN ELECTRODES To 3rd 96pins of SCAN ELECTRODES To 4th 96pins of TO SC-BOARD (SC41) 1 2 1 4 6 5 3 UP Vf5 Vf TH-42PV65C SU-Board (2 of 2) Schematic Diagram TH-42PV65C SU-Board (2 of 2) Schematic Diagram 119 14.58.SD 电路板 （1/2）线路图 TERM SIDE TERM SIDE AB_382 AB_381 AB_380 AB_379 AB_378 AB_377 AB_376 AB_375 AB_374 AB_373 AB_372 AB_371 AB_370 AB_369 AB_368 AB_367 AB_366 AB_365 AB_364 AB_363 AB_362 AB_361 AB_360 AB_358 AB_359 AB_357 AB_355 AB_356 AC_318 AC_317 AC_316 AC_315 AC_314 AC_313 AC_312 AC_311 AC_310 AC_309 AC_308 AC_307 AC_306 AC_305 AC_304 AC_303 AC_302 AC_301 AC_300 AC_299 AC_298 AC_297 AC_296 AC_294 AC_295 AC_293 AC_291 AC_292 AD_254 AD_253 AD_252 AD_251 AD_250 AD_249 AD_248 AD_247 AD_246 AD_245 AD_244 AD_243 AD_242 AD_241 AD_240 AD_239 AD_238 AD_237 AD_236 AD_235 AD_234 AD_233 AD_232 AD_230 AD_231 AD_229 AD_227 AB_365 AB_367 AB_369 AB_371 AB_373 AB_375 AB_377 AB_379 AB_381 AB_383 AB_366 AB_368 AB_370 AB_372 AB_374 AB_376 AB_380 AB_382 AB_341 AB_343 AB_345 AB_347 AB_349 AB_351 AB_353 AB_355 AB_357 AB_359 AB_361 AB_363 AB_342 AB_344 AB_346 AB_348 AB_350 AB_352 AB_354 AB_356 AB_358 AB_360 AB_362 AB_364 AB_321 AB_323 AB_325 AB_327 AB_329 AB_331 AB_333 AB_335 AB_337 AB_339 AB_322 AB_324 AB_326 AB_328 AB_330 AB_332 AB_334 AB_336 AB_338 AB_340 AC_319 AC_317 AC_316 AC_320 AC_318 AB_384 AB_383 AC_293 AC_295 AC_297 AC_299 AC_301 AC_303 AC_305 AC_307 AC_309 AC_311 AC_313 AC_315 AC_294 AC_296 AC_298 AC_300 AC_302 AC_304 AC_306 AC_308 AC_310 AC_312 AC_314 AC_281 AC_283 AC_287 AC_285 AC_282 AC_284 AC_288 AC_286 AC_289 AC_291 AC_257 AC_259 AC_261 AC_263 AC_265 AC_267 AC_269 AC_271 AC_273 AC_275 AC_277 AC_279 AC_258 AC_260 AC_262 AC_264 AC_266 AC_268 AC_270 AC_272 AC_274 AC_276 AC_278 AC_280 AD_256 AC_320 AC_319 AD_254 AD_252 AD_250 AD_248 AD_246 AD_244 AD_242 AD_240 AD_238 AD_236 AD_234 AD_232 AD_253 AD_255 AD_251 AD_249 AD_247 AD_245 AD_243 AD_241 AD_239 AD_237 AD_235 AD_233 AD_230 AD_228 AD_226 AD_224 AD_222 AD_220 AD_218 AD_216 AD_214 AD_212 AD_210 AD_208 AD_231 AD_229 AD_227 AD_225 AD_223 AD_221 AD_219 AD_217 AD_215 AD_213 AD_211 AD_209 AD_206 AD_204 AD_202 AD_200 AD_198 AD_196 AD_194 AD_207 AD_205 AD_203 AD_201 AD_199 AD_197 AD_195 AD_193 AD_256 AD_255 AB_378 AB_384 AC_292 AC_290 AB_321 AB_323 AB_324 AB_325 AB_326 AB_327 AB_328 AB_329 AB_330 AB_331 AB_332 AB_333 AB_334 AB_335 AB_336 AB_337 AB_338 AB_339 AB_340 AB_341 AB_342 AB_343 AB_344 AB_345 AB_346 AB_322 AB_347 AB_348 AB_349 AB_350 AB_351 AB_352 AB_353 AB_354 AC_257 AC_258 AC_259 AC_260 AC_261 AC_262 AC_263 AC_264 AC_265 AC_266 AC_267 AC_268 AC_269 AC_270 AC_271 AC_272 AC_273 AC_274 AC_275 AC_276 AC_277 AC_278 AC_279 AC_280 AC_281 AC_282 AC_283 AC_284 AC_285 AC_286 AC_287 AC_288 AC_289 AC_290 AD_193 AD_194 AD_195 AD_196 AD_197 AD_198 AD_199 AD_200 AD_201 AD_202 AD_203 AD_204 AD_205 AD_206 AD_207 AD_208 AD_209 AD_210 AD_211 AD_212 AD_213 AD_214 AD_215 AD_216 AD_217 AD_218 AD_219 AD_220 AD_221 AD_222 AD_223 AD_224 AD_226 AD_225 AD_228 AA_SO7 AA_SO7 AA_SO8 AA_SO8 AA_SO9 AA_CLK AA_CL AA_PRO AA_CLK AA_CL AA_PRO AA_CLK AA_CL AA_PRO AA_SI 140V A24 A56 SD1 B36 B20 B4 A36 A20 A4 B39 B23 B7 A39 A23 A7 B42 B26 B10 A42 A26 A10 B45 B29 B13 A45 A29 A13 B48 B32 B16 A48 A32 A16 B35 B19 B3 A35 A19 A3 B38 B22 B6 A38 A22 A6 B41 B25 B9 A41 A25 A9 B44 B28 B12 A44 A28 A12 B47 B31 B15 A47 A31 A15 B34 B18 B2 A34 A18 A1 B37 B21 B5 A37 A21 A5 B40 B24 B8 A40 A24 A2 A8 B43 B27 B11 A43 A27 A11 B46 B30 B14 A46 A30 A14 B33 B17 B1 A33 A17 A12 A70 A47 AN16072A-VT IC6951 1 OUT3 2 OUT4 3 OUT5 4 OUT6 5 OUT7 6 OUT8 7 OUT9 8 OUT10 9 OUT11 10 OUT12 11 OUT13 12 OUT14 13 OUT15 14 OUT16 15 OUT17 16 OUT18 17 OUT19 18 OUT20 19 OUT21 20 OUT22 21 OUT23 22 OUT24 23 OUT25 24 OUT26 25 OUT27 26 OUT28 27 OUT29 28 OUT30 29 OUT31 30 OUT32 31 N.C. 32 VDDH 33 VDDH 34 N.C. 35 GND 36 GND 37 GND 38 TEST 39 GND 40 GND 41 GND 42 N.C. 43 VDDH 44 VDDH 45 N.C. 46 OUT33 47 OUT34 48 OUT35 49 OUT36 50 OUT37 51 OUT38 52 OUT39 53 OUT40 54 OUT41 55 OUT42 56 OUT43 57 OUT44 58 OUT45 59 OUT46 60 OUT47 61 OUT48 62 OUT49 63 OUT50 64 OUT51 65 OUT52 66 OUT53 67 OUT54 68 OUT55 69 OUT56 70 OUT57 71 OUT58 72 OUT59 73 OUT60 74 OUT61 75 OUT62 76 OUT63 77 OUT64 78 N.C. 79 VDDH 80 VDDH 81 N.C. 82 GND 83 GND 84 DIR 85 SO 86 CLK 87 LAT 88 VDD 89 OC1 90 OC2 91 SI 92 CLR 93 GND 94 GND 95 N.C. 96 VDDH 97 VDDH 98 N.C. 99 OUT1 100 OUT2 A1 D6954 B0ECHP000003 A32 C6983 250V 1u A35 A23 A38 A10 A40 R6986 220k A14 A75 A2 C6982 250V 1u A46 A16 A6 D6953 B0ECHP000003 A76 A37 A33 A53 AN16072A-VT IC6952 1 OUT3 2 OUT4 3 OUT5 4 OUT6 5 OUT7 6 OUT8 7 OUT9 8 OUT10 9 OUT11 10 OUT12 11 OUT13 12 OUT14 13 OUT15 14 OUT16 15 OUT17 16 OUT18 17 OUT19 18 OUT20 19 OUT21 20 OUT22 21 OUT23 22 OUT24 23 OUT25 24 OUT26 25 OUT27 26 OUT28 27 OUT29 28 OUT30 29 OUT31 30 OUT32 31 N.C. 32 VDDH 33 VDDH 34 N.C. 35 GND 36 GND 37 GND 38 TEST 39 GND 40 GND 41 GND 42 N.C. 43 VDDH 44 VDDH 45 N.C. 46 OUT33 47 OUT34 48 OUT35 49 OUT36 50 OUT37 51 OUT38 52 OUT39 53 OUT40 54 OUT41 55 OUT42 56 OUT43 57 OUT44 58 OUT45 59 OUT46 60 OUT47 61 OUT48 62 OUT49 63 OUT50 64 OUT51 65 OUT52 66 OUT53 67 OUT54 68 OUT55 69 OUT56 70 OUT57 71 OUT58 72 OUT59 73 OUT60 74 OUT61 75 OUT62 76 OUT63 77 OUT64 78 N.C. 79 VDDH 80 VDDH 81 N.C. 82 GND 83 GND 84 DIR 85 SO 86 CLK 87 LAT 88 VDD 89 OC1 90 OC2 91 SI 92 CLR 93 GND 94 GND 95 N.C. 96 VDDH 97 VDDH 98 N.C. 99 OUT1 100 OUT2 A20 A44 A41 A45 C6952 16V 1u A43 A11 A68 A67 A39 A3 A31 A21 A63 A72 A36 A77 C6985 250V 1u A66 A7 A28 A73 A61 A62 A19 C6955 16V 1u A57 AN16072A-VT IC6953 1 OUT3 2 OUT4 3 OUT5 4 OUT6 5 OUT7 6 OUT8 7 OUT9 8 OUT10 9 OUT11 10 OUT12 11 OUT13 12 OUT14 13 OUT15 14 OUT16 15 OUT17 16 OUT18 17 OUT19 18 OUT20 19 OUT21 20 OUT22 21 OUT23 22 OUT24 23 OUT25 24 OUT26 25 OUT27 26 OUT28 27 OUT29 28 OUT30 29 OUT31 30 OUT32 31 N.C. 32 VDDH 33 VDDH 34 N.C. 35 GND 36 GND 37 GND 38 TEST 39 GND 40 GND 41 GND 42 N.C. 43 VDDH 44 VDDH 45 N.C. 46 OUT33 47 OUT34 48 OUT35 49 OUT36 50 OUT37 51 OUT38 52 OUT39 53 OUT40 54 OUT41 55 OUT42 56 OUT43 57 OUT44 58 OUT45 59 OUT46 60 OUT47 61 OUT48 62 OUT49 63 OUT50 64 OUT51 65 OUT52 66 OUT53 67 OUT54 68 OUT55 69 OUT56 70 OUT57 71 OUT58 72 OUT59 73 OUT60 74 OUT61 75 OUT62 76 OUT63 77 OUT64 78 N.C. 79 VDDH 80 VDDH 81 N.C. 82 GND 83 GND 84 DIR 85 SO 86 CLK 87 LAT 88 VDD 89 OC1 90 OC2 91 SI 92 CLR 93 GND 94 GND 95 N.C. 96 VDDH 97 VDDH 98 N.C. 99 OUT1 100 OUT2 A4 A48 A17 A49 A9 C6984 250V 1u A80 A22 A34 A69 A58 A13 A54 SD2 B36 B20 B4 A36 A20 A4 B39 B23 B7 A39 A23 A7 B42 B26 B10 A42 A26 A10 B45 B29 B13 A45 A29 A13 B48 B32 B16 A48 A32 A16 B35 B19 B3 A35 A19 A3 B38 B22 B6 A38 A22 A6 B41 B25 B9 A41 A25 A9 B44 B28 B12 A44 A28 A12 B47 B31 B15 A47 A31 A15 B34 B18 B2 A34 A18 A1 B37 B21 B5 A37 A21 A5 B40 B24 B8 A40 A24 A2 A8 B43 B27 B11 A43 A27 A11 B46 B30 B14 A46 A30 A14 B33 B17 B1 A33 A17 C6957 16V 1u A25 A55 A52 A30 A79 A51 C6951 50V 1000p A29 A27 R6955 220 A15 A8 A18 A64 A50 R6984 10k A71 A74 R6951 100 A5 A78 A60 A65 A42 A26 A59 R6959 220 D6951 MAZ80560HL D6952 MAZ80560HL C6964 50V 220p C6965 50V 220p Vfo Vf5 VF5V VF5V Vf 8 2 1 A 3 B D E C 7 4 5 6 Vf Vf COMPONENT SIDE (LOWER) FOIL SIDE (UPPER) PDP SCAN DRIVER S/P 64bit PDP SCAN DRIVER S/P 64bit PDP SCAN DRIVER S/P 64bit SCAN ELECTRODES To 1st 96pins of To 2nd 96pins of SCAN ELECTRODES Vf(High Voltage Floting GND) Vfo(Vscn Out) (Vscn voltage) Vf(High Voltage Floting GND) Vscn (SC42) SD42(Card Edge 80Pin) TO SC-BOARD DOWN SD-BOARD TNPA3819 (1/2) 2 1 4 6 5 3 TH-42PV65C SD-Board (1 of 2) Schematic Diagram TH-42PV65C SD-Board (1 of 2) Schematic Diagram 120 14.59.SD 电路板 （2/2）线路图 TERM SIDE TERM SIDE AE_190 AE_189 AE_188 AE_187 AE_186 AE_185 AE_184 AE_183 AE_182 AE_181 AE_180 AE_179 AE_178 AE_177 AE_176 AE_175 AE_174 AE_173 AE_172 AE_171 AE_170 AE_169 AE_168 AE_166 AE_167 AE_165 AE_163 AE_164 AF_126 AF_125 AF_124 AF_123 AF_122 AF_121 AF_120 AF_119 AF_118 AF_117 AF_116 AF_115 AF_114 AF_113 AF_112 AF_111 AF_110 AF_109 AF_108 AF_107 AF_106 AF_105 AF_104 AF_102 AF_103 AF_101 AF_99 AF_100 AG_62 AG_61 AG_60 AG_59 AG_58 AG_57 AG_56 AG_55 AG_54 AG_53 AG_52 AG_51 AG_50 AG_49 AG_48 AG_47 AG_46 AG_45 AG_44 AG_43 AG_42 AG_41 AG_40 AG_38 AG_39 AG_37 AG_35 AG_36 AE_187 AE_185 AE_183 AE_188 AE_186 AE_184 AE_182 AE_191 AE_192 AE_189 AE_190 AE_175 AE_173 AE_181 AE_179 AE_177 AE_176 AE_174 AE_172 AE_180 AE_178 AE_161 AE_159 AE_163 AE_164 AE_162 AE_160 AE_158 AE_165 AE_171 AE_169 AE_167 AE_170 AE_168 AE_166 AE_151 AE_157 AE_155 AE_153 AE_149 AE_152 AE_156 AE_154 AE_148 AE_150 AE_192 AE_191 AE_137 AE_135 AE_140 AE_138 AE_136 AE_134 AE_141 AE_143 AE_145 AE_147 AE_144 AE_146 AE_139 AE_142 AE_133 AE_131 AE_129 AF_127 AF_125 AF_123 AE_132 AE_130 AF_128 AF_126 AF_124 AF_113 AF_111 AF_114 AF_112 AF_110 AF_117 AF_121 AF_119 AF_122 AF_120 AF_115 AF_116 AF_118 AF_109 AF_107 AF_105 AF_103 AF_101 AF_99 AF_108 AF_106 AF_104 AF_102 AF_100 AF_97 AF_98 AF_94 AF_96 AF_92 AF_90 AF_93 AF_95 AF_91 AF_128 AF_127 AF_88 AF_86 AF_84 AF_82 AF_80 AF_78 AF_76 AF_74 AF_72 AF_70 AF_68 AF_66 AF_89 AF_87 AF_85 AF_83 AF_81 AF_79 AF_77 AF_75 AF_73 AF_71 AF_69 AF_67 AG_61 AG_63 AG_59 AG_57 AG_55 AG_53 AG_51 AG_49 AG_47 AG_45 AG_43 AG_41 AG_64 AG_62 AG_60 AG_58 AG_56 AG_54 AG_52 AG_50 AG_48 AG_46 AG_44 AG_42 AF_65 AG_39 AG_37 AG_35 AG_33 AG_31 AG_29 AG_27 AG_25 AG_23 AG_21 AG_19 AG_17 AG_40 AG_38 AG_36 AG_34 AG_32 AG_30 AG_28 AG_26 AG_24 AG_22 AG_20 AG_18 AG_64 AG_63 AG_15 AG_13 AG_11 AG_9 AG_7 AG_5 AG_3 AG_1 AG_16 AG_14 AG_12 AG_10 AG_8 AG_6 AG_4 AG_2 AE_130 AE_129 AE_132 AE_133 AE_134 AE_135 AE_136 AE_137 AE_138 AE_139 AE_140 AE_141 AE_142 AE_143 AE_144 AE_145 AE_146 AE_147 AE_148 AE_149 AE_150 AE_151 AE_152 AE_153 AE_154 AE_131 AE_155 AE_156 AE_157 AE_158 AE_159 AE_160 AE_162 AE_161 AF_65 AF_66 AF_67 AF_68 AF_69 AF_70 AF_71 AF_72 AF_73 AF_74 AF_75 AF_76 AF_77 AF_78 AF_79 AF_80 AF_81 AF_82 AF_83 AF_84 AF_85 AF_86 AF_87 AF_88 AF_89 AF_90 AF_91 AF_92 AF_93 AF_94 AF_95 AF_96 AF_97 AF_98 AG_1 AG_2 AG_3 AG_4 AG_5 AG_6 AG_7 AG_8 AG_9 AG_10 AG_11 AG_12 AG_13 AG_14 AG_15 AG_16 AG_17 AG_18 AG_19 AG_20 AG_21 AG_22 AG_23 AG_24 AG_25 AG_26 AG_27 AG_28 AG_29 AG_30 AG_31 AG_32 AG_34 AG_33 AA_SO9 AA_SO10 AA_SO11 AA_CLK AA_CL AA_PRO AA_CLK AA_CL AA_PRO AA_CLK AA_CL AA_PRO AA_SI AA_CLK AA_PRO AA_CL AA_SO10 AA_SO11 R6953 22 R6967 220 R6983 10k R6952 22 R6981 10k SD4 B36 B20 B4 A36 A20 A4 B39 B23 B7 A39 A23 A7 B42 B26 B10 A42 A26 A10 B45 B29 B13 A45 A29 A13 B48 B32 B16 A48 A32 A16 B35 B19 B3 A35 A19 A3 B38 B22 B6 A38 A22 A6 B41 B25 B9 A41 A25 A9 B44 B28 B12 A44 A28 A12 B47 B31 B15 A47 A31 A15 B34 B18 B2 A34 A18 A1 B37 B21 B5 A37 A21 A5 B40 B24 B8 A40 A24 A2 A8 B43 B27 B11 A43 A27 A11 B46 B30 B14 A46 A30 A14 B33 B17 B1 A33 A17 C6963 16V 1u 1 2 3 4 5 6 7 8 9 C6958 16V 1u C6981 50V 1000p R6971 220 R6982 10k SD3 B36 B20 B4 A36 A20 A4 B39 B23 B7 A39 A23 A7 B42 B26 B10 A42 A26 A10 B45 B29 B13 A45 A29 A13 B48 B32 B16 A48 A32 A16 B35 B19 B3 A35 A19 A3 B38 B22 B6 A38 A22 A6 B41 B25 B9 A41 A25 A9 B44 B28 B12 A44 A28 A12 B47 B31 B15 A47 A31 A15 B34 B18 B2 A34 A18 A1 B37 B21 B5 A37 A21 A5 B40 B24 B8 A40 A24 A2 A8 B43 B27 B11 A43 A27 A11 B46 B30 B14 A46 A30 A14 B33 B17 B1 A33 A17 AN16072A-VT IC6954 1 OUT3 2 OUT4 3 OUT5 4 OUT6 5 OUT7 6 OUT8 7 OUT9 8 OUT10 9 OUT11 10 OUT12 11 OUT13 12 OUT14 13 OUT15 14 OUT16 15 OUT17 16 OUT18 17 OUT19 18 OUT20 19 OUT21 20 OUT22 21 OUT23 22 OUT24 23 OUT25 24 OUT26 25 OUT27 26 OUT28 27 OUT29 28 OUT30 29 OUT31 30 OUT32 31 N.C. 32 VDDH 33 VDDH 34 N.C. 35 GND 36 GND 37 GND 38 TEST 39 GND 40 GND 41 GND 42 N.C. 43 VDDH 44 VDDH 45 N.C. 46 OUT33 47 OUT34 48 OUT35 49 OUT36 50 OUT37 51 OUT38 52 OUT39 53 OUT40 54 OUT41 55 OUT42 56 OUT43 57 OUT44 58 OUT45 59 OUT46 60 OUT47 61 OUT48 62 OUT49 63 OUT50 64 OUT51 65 OUT52 66 OUT53 67 OUT54 68 OUT55 69 OUT56 70 OUT57 71 OUT58 72 OUT59 73 OUT60 74 OUT61 75 OUT62 76 OUT63 77 OUT64 78 N.C. 79 VDDH 80 VDDH 81 N.C. 82 GND 83 GND 84 DIR 85 SO 86 CLK 87 LAT 88 VDD 89 OC1 90 OC2 91 SI 92 CLR 93 GND 94 GND 95 N.C. 96 VDDH 97 VDDH 98 N.C. 99 OUT1 100 OUT2 AN16072A-VT IC6955 1 OUT3 2 OUT4 3 OUT5 4 OUT6 5 OUT7 6 OUT8 7 OUT9 8 OUT10 9 OUT11 10 OUT12 11 OUT13 12 OUT14 13 OUT15 14 OUT16 15 OUT17 16 OUT18 17 OUT19 18 OUT20 19 OUT21 20 OUT22 21 OUT23 22 OUT24 23 OUT25 24 OUT26 25 OUT27 26 OUT28 27 OUT29 28 OUT30 29 OUT31 30 OUT32 31 N.C. 32 VDDH 33 VDDH 34 N.C. 35 GND 36 GND 37 GND 38 TEST 39 GND 40 GND 41 GND 42 N.C. 43 VDDH 44 VDDH 45 N.C. 46 OUT33 47 OUT34 48 OUT35 49 OUT36 50 OUT37 51 OUT38 52 OUT39 53 OUT40 54 OUT41 55 OUT42 56 OUT43 57 OUT44 58 OUT45 59 OUT46 60 OUT47 61 OUT48 62 OUT49 63 OUT50 64 OUT51 65 OUT52 66 OUT53 67 OUT54 68 OUT55 69 OUT56 70 OUT57 71 OUT58 72 OUT59 73 OUT60 74 OUT61 75 OUT62 76 OUT63 77 OUT64 78 N.C. 79 VDDH 80 VDDH 81 N.C. 82 GND 83 GND 84 DIR 85 SO 86 CLK 87 LAT 88 VDD 89 OC1 90 OC2 91 SI 92 CLR 93 GND 94 GND 95 N.C. 96 VDDH 97 VDDH 98 N.C. 99 OUT1 100 OUT2 C6961 16V 1u R6963 220 AN16072A-VT IC6956 1 OUT3 2 OUT4 3 OUT5 4 OUT6 5 OUT7 6 OUT8 7 OUT9 8 OUT10 9 OUT11 10 OUT12 11 OUT13 12 OUT14 13 OUT15 14 OUT16 15 OUT17 16 OUT18 17 OUT19 18 OUT20 19 OUT21 20 OUT22 21 OUT23 22 OUT24 23 OUT25 24 OUT26 25 OUT27 26 OUT28 27 OUT29 28 OUT30 29 OUT31 30 OUT32 31 N.C. 32 VDDH 33 VDDH 34 N.C. 35 GND 36 GND 37 GND 38 TEST 39 GND 40 GND 41 GND 42 N.C. 43 VDDH 44 VDDH 45 N.C. 46 OUT33 47 OUT34 48 OUT35 49 OUT36 50 OUT37 51 OUT38 52 OUT39 53 OUT40 54 OUT41 55 OUT42 56 OUT43 57 OUT44 58 OUT45 59 OUT46 60 OUT47 61 OUT48 62 OUT49 63 OUT50 64 OUT51 65 OUT52 66 OUT53 67 OUT54 68 OUT55 69 OUT56 70 OUT57 71 OUT58 72 OUT59 73 OUT60 74 OUT61 75 OUT62 76 OUT63 77 OUT64 78 N.C. 79 VDDH 80 VDDH 81 N.C. 82 GND 83 GND 84 DIR 85 SO 86 CLK 87 LAT 88 VDD 89 OC1 90 OC2 91 SI 92 CLR 93 GND 94 GND 95 N.C. 96 VDDH 97 VDDH 98 N.C. 99 OUT1 100 OUT2 R6954 22 R6985 220k C6966 50V 220p C6967 50V 220p C6968 50V 220p PRO FSI FCLK FCL 15 11 10 13 8 14 12 9 PDP SCAN DRIVER S/P 64bit PDP SCAN DRIVER S/P 64bit PDP SCAN DRIVER S/P 64bit To 4th 96pins of To 3rd 96pins of SCAN ELECTRODES SCAN ELECTRODES 46 SC-BOARD SD (SC46) TO FSI FCL FCLK PRO VF5V VF5V Vf Vfo Vf5 DOWN SD-BOARD TNPA3819 (2/2) Vf Vf5 4 6 5 3 2 1 TH-42PV65C SD-Board (2 of 2) Schematic Diagram TH-42PV65C SD-Board (2 of 2) Schematic Diagram 121 14.60.SS 和 S 电路板方框图 D6221 TPVSUS D6253 TP15V TPSS1 TPVE TPVDA D6255 R6113 Q6051,Q6052 Q6141-Q6142 +15V DRIVER LED(G) FET DRIVER VCC FET SS IC6191 TPSS1 SIGNAL WAVE 1 Q6103,Q6104 4 Vsus Gen. 34 Q6021-Q6023 VCC Vda Q6001-Q6003 SS_SOS8 OUTPUT VSUS TPSS1 VE 1 2 8 STB12V VCC Vda DRIVER TO C23 Ve Gen. VCC 10 VCC 3 IC6251 STB PS IC6131 12 Ve2 BUFFER FET IC6241 P12 SS 5 7 11 3 8 12 1 2 4 6 23 SS Adj. (+150V) VE Gen. TPVE IC6221 Q6221,Q6222 VR6000 ENERGY RECOVERY FET OUTPUT FET COMPARATOR OUTPUT FET SS SUSTAIN DRIVE Vsus 11 SS 1 TO P11 NO USE UMH UEH SS_SOS8 5V Vda Vda NUEL USH USL UML Q6146-Q6147 IC6151 Q6041,Q6042 L6011-L6013 L6001-L6003 VCC FET OUTPUT IC6211 (+5V) IN Q6112,Q6114 Ve2 Gen. FET DRIVER SUSTAIN ELECTRODE PANEL SS43 SS41 SS44 SS42 Q6101,Q6102 Q6111 LED BLINKING : 8 TIMES ENERGY RECOVERY SOS DET TH-42PV65C SS and S-Board Block Diagram TH-42PV65C SS and S-Board Block Diagram PUSH SW2500 S34 S POWER SWITCH STB PS POWER SWITCH 3 1 STB12V 122 14.61.SS 和 S 电路板线路图 + + TERM SIDE TERM SIDE + + + + + + REF K A + + + TERM SIDE TERM SIDE + + + 5V 15V 0-200V 200V 200V 15V 75V 75V Q6111 2SK326800L G D S R6004 15 C6134 25V 4.7u TP30 L6082 G0ZZ00002183 R6052 10 Q6172 B1ADRD000001 R6141 10k VR6000 10k 1 2 3 100 R6194 C6212 25V 4.7u Q6103 B1DFKM000002 G D S TP22 IC6211 C0ZBZ0001325 1 Vcc 2 IN 3 GND 4 LO 5 NC 6 VS 7 HO 8 VB TP25 R6112 47 R6182 10k L6271 G0ZZ00002183 C0JBAZ000005 IC6241 1G~ 1 2 1A1 3 2Y4 4 1A2 5 2Y3 6 1A3 7 2Y2 8 1A4 9 2Y1 10 GND 11 2A1 12 1Y4 13 2A2 14 1Y3 15 2A3 16 1Y2 17 2A4 18 1Y1 19 2G~ 20 VCC C6155 25V 4.7u R6246 4.7k D6152 B0ECHP000003 L6104 J0JJC0000011 Q6171 B1ABRD000003 C6213 25V 470u Q6146 2SC5824T100R Q6022 B1JADN000001 L6086 G0ZZ00002183 L6065 G0ZZ00002183 TP26 TP28 Q6147 2SA2071T100Q C6195 25V 4.7u D6253 LNJ301MPUJA TP2 TP6 150 R6214 TP13 R6152 100 D6103 B0JCME000037 L6062 G0ZZ00002183 C6012 220V 200u R6231 0 L6084 G0ZZ00002183 SS42 1 2 3 4 5 6 7 8 9 10 11 12 13 R6256 1.5k D6223 MA2J11100L ZA6001 K4CD01000011 D6151 B0ECHP000003 ZA6005 K4CD01000011 R6032 82k L6068 G0ZZ00002183 R6181 10 L6003 1.9u R6227 16k L6064 G0ZZ00002183 R6172 10k R6002 15 SS41 1 2 3 4 5 6 7 8 9 10 11 12 13 R6142 10k 150 R6134 TP24 L6081 G0ZZ00002183 1 R6160 R6106 100 R6105 100 R6025 15 TP11 D6251 MAZ83300ML TP32 L6012 1.9u Q6141 B1ABNF000006 D6102 B0JCME000037 TP10 R6027 15 C6214 25V 470u R6258 2.2k Q6001 B1JADN000001 C6251 16V 1u D6131 B0ECHP000003 R6255 1.2k TP23 R6251 10k C6013 220V 200u C6031 250V 2.2u TP16 R6173 10k 100 R6193 150 R6153 L6002 1.9u 200u 220V C6015 R6103 100 C6011 220V 200u L6085 G0ZZ00002183 C6221 50V 0.1u D6192 B0ECHP000003 TP5 R6131 100 Q6051 B1JADN000002 R6222 10k C6001 630V 5600p L6241 G0ZZ00002183 R6243 47 C6154 25V 4.7u D6191 B0ECHP000003 R6156 0 R6245 47 R6244 4.7k C6272 25V 220u R6022 100 R6226 16k L6262 G0ZZ00002183 R6242 EXB38V472JV R6042 10 TP17 L6272 G0ZZ00002183 C6273 25V 220u R6024 15 R6155 0 R6044 10 R6257 10k L6087 G0ZZ00002183 R6228 5.6k D6132 B0ECHP000003 L6061 G0ZZ00002183 C0DBEMB00005 IC6221 R6023 15 TP20 R6053 10 D6252 MAZ83300ML L6102 J0JJC0000011 Q6101 B1DFKM000002 G D S ZA6002 K4CD01000011 R6005 15 R6034 27k TP12 R6001 15 R6213 100 R6033 56k R6132 100 C6261 100V 220u D6221 B0ECHP000003 Q6112 B1DFKM000002 G D S 150 R6133 1 R6157 R6020 100 L6101 J0JJC0000011 Q6142 B1ADNF000006 Q6023 B1JADN000001 D6082 B0HBSN000008 TP14 D6032 MA2J11100L TP7 R6241 EXB38V470JV Q6222 2SC3063000RL R6003 15 100k R6196 TP1 C0ZBZ0000895 IC6131 1 LO 2 GND 3 VCC 4 NC 5 NC 6 VS 7 VB 8 HO 9 NC 10 NC 11 NC 12 HIN 13 NC 14 LIN 15 GND 16 NC TP3 D6101 B0JCME000037 R6104 100 L6221 G0ZZ00002183 R6006 15 R6041 10 C6132 25V 4.7u R6223 12k TP9 D6222 MA2J11100L C0ZBZ0001324 IC6151 1 LO 2 Vcom 3 VCC2 4 NC 5 NC 6 VS 7 VB 8 HO 9 NC 10 NC 11 VCC 12 HIN 13 NC 14 LIN 15 GND 16 NC TP18 R6026 15 TP8 150 R6154 R6102 100 C6135 25V 4.7u R6151 100 C0ZBZ0000895 IC6191 1 LO 2 GND 3 VCC 4 NC 5 NC 6 VS 7 VB 8 HO 9 NC 10 NC 11 NC 12 HIN 13 NC 14 LIN 15 GND 16 NC L6011 1.9u Q6052 B1JADN000002 C6021 630V 5600p R6051 10 C6152 25V 4.7u C6242 16V 1u R6254 8.2k R6054 10 D6062 RF2001T3DFF55 Q6042 B1JADN000002 R6031 82k R6146 10k Q6251 2SD0601A0L R6101 100 D6061 RF2001T3DFF55 Q6021 B1JADN000001 R6021 15 1 2 3 4 5 6 7 8 9 10 C6153 25V 4.7u TP21 Q6003 B1JADN000001 R6183 10k L6001 1.9u R6116 10k 1 2 3 C6262 100V 220u L6013 1.9u Q6102 B1DFKM000002 G D S 1 2 3 4 5 6 7 8 9 10 11 12 TP31 L6067 G0ZZ00002183 C6194 25V 4.7u D6051 B0ECHP000003 D6254 MAZ80510LL D6153 B0ECHP000003 200u 220V C6014 L6066 G0ZZ00002183 R6147 10k TP19 R6136 10 R6113 220k R6261 100k R6043 10 D6041 B0ECHP000003 Q6181 B1ABRD000003 1 R6158 Q6182 B1ADRD000001 L6103 G0ZZ00002183 D6021 RF2001T3DFF55 Q6002 B1JADN000001 D6211 B0JCME000037 L6088 G0ZZ00002183 R6253 39k TP15 L6083 G0ZZ00002183 R6252 39k R6171 10 TP29 R6232 1.2k IC6251 C0BBBA000022 1 2 3 4 5 6 7 8 R6225 20k R6111 47 R6135 10 SS43 1 2 3 4 5 6 7 8 9 10 11 12 13 B0ECHP000003 D6092 Q6041 B1JADN000002 D6081 RF2001T3DFF55 100k R6195 D6001 B0HBSN000008 SS44 1 2 3 4 5 6 7 8 9 10 11 12 13 TP27 L6063 G0ZZ00002183 D6255 MA2J11100L R6192 100 C6243 50V 0.01u C6211 25V 4.7u D6071 MA3DF30000LZ D6072 MA3DF30000LZ D6091 MA3DF30000LZ C6241 25V 470u C6111 200V 220u C6112 200V 220u Q6114 B1DFKM000002 G D S R6114 47 L6211 J0JJC0000011 L6212 J0JJC0000011 Q6104 H5N2307LSTL-E G D S D6104 B0JCME000037 R6107 100 R6108 100 L6105 J0JJC0000011 Q6105 2SC5824T100R Q6106 2SA2071T100Q 10 R6109 10k R6110 R6229 16k C6201 250V 4u C6202 250V 4u C6041 16V 1u C6042 16V 1u C6043 16V 1u C6044 16V 1u C6151 25V 1u C6192 25V 1u C6271 25V 1u R6191 100 R6062 220k R6061 220k 1 3 Q6221 2SD1263AP0LB D6154 B0ECHP000003 1 R6159 D6193 B0ECHP000003 C6022 630V 5600p TP15V TPVDA - + - + (GREEN LED) TPSS1 TPVe TPVSUS C2-BOARD (C23) TO BUFFER FET DRIVER FET DRIVER FET DRIVER VE GEN. FET DRIVER COMPARATOR 5 D E 4 3 B 7 6 2 A 1 C 8 SS-BOARD TNPA3815AJ Vda Vda GND GND GND NC STB12V STB PS +15V NC 5V NUEL USL USH UEH UMH UML SS_SOS8 GND NC Vda Vda SUSTAIN ELECTRODE PANEL TO GND NC Vsus P-BOARD (P11) TO SS 11 12 SS SS 34 SS 23 (P12) P-BOARD TO 189.0 0 0 0 12.0 0 15.0 0 75.5 0 12.0 0 75.5 3.7 0 0.5 0 0.5 5.0 0.6 0.9 0.4 75.5 75.5 1.7 USE NO TH-42PV65C SS and S-Board Schematic Diagram TH-42PV65C SS and S-Board Schematic Diagram PUSH S1 1 2 3 SW2500 K0F162B00002 S-BOARD TNPA3763AC POWER SW GND 12V STB_PS 0 12.0 12.0 123 15 部件布置及机械部件更换清单 15.1. 部件布置 124 15.2. 包装分解图 (1) 125 15.3. 包装分解图 (2) 126 15.4. 包装分解图 (3) 127 15.5. 维修部品表 参考号 部品号 部品名称 & 说明 件数 备注 1 EAS12S13A 喇叭 2 J0KF00000038 磁环 1 2 K2CK3DH00028 电源线 1 K5D802BNA005 保险丝 2 3 L6FALEFH0041 风扇元件 （80mm） 2 4 MC106H23F9 42HD PDP 屏 1 5 N2QAYB000041 遥控器 1 6 R6PND/2SP 干电池 2 TBMA185 PANASONIC 标牌 1 TBMG433 机种铭牌 1 TBMU630 指示片 A 1 TBMU631 指示片 B 1 TBMU632 后面端子片 A 1 7 TBXA49301 操作开关 1 8 TBXA49402 电源开关 1 9 TESA280 门弹簧 1 10 TESD076 电源开关弹簧 1 THEL037N 螺丝 1 THEL0429 螺丝 30 THEL044N 螺丝 1 THEL047J 螺丝 (HDMI 端子 ) 2 THTD013N 螺丝 6 THTF011N 螺丝 70 11 TKEA15701 面框 1 12 TKGA5288 前面玻璃 1 13 TKKC5245 导光板 1 14 TKKL5344 M8 垫片盖 4 TKKL5361 调整盖 1 15 TKPA98101 接入口盖 1 16 TKPB02602 门盖 1 17 TKRA52601 后盖把手 2 18 TKUX10601 后盖 1 TMME226 电源线夹 1 19 TMME258 线夹 2 TMMX130 M8 垫片 4 20 TMZX5087 台座安装块 2 21 TPCB94805 包装箱本体 1 22 TPCB94901 包装箱底箱 1 23 TPD0A9002L 箱扣 4 24 TPDA1324 缓冲材 （顶面） 1 25 TPDA1325-1 缓冲材 （底面） 1 26 TPDF0764 附件盒 1 27 TPDF1621 顶盖 1 28 TPEH165 保护袋 1 29 TPEH277 顶面保护片 4 TQD1712010 合格票 1 TQFD239 线夹标签 1 TQFD291 CCTV 标贴 1 30 TQZC935 说明书 1 TQZF163 保修证 1 TSXL520 FPC DG1-H1 1 TSXL521 FPC DG15-HC15 1 TSXL522 FPC DG20-PA20 1 TSXL554 68PFFC(S) 1 TSXL555 80P FFC(S) 1 TSXL597 30PFFC(C-C) 1 TSXL607 FFC D3-DG3 1 TXAUX01GLTC 高频头块 半成品 1 31 TXAUX02BJTC AC 接入口 （半）包装入 1 TXJ/G1BJTU 线束 (G1-K1) 1 TXJ/G3BJTU 线束 （G3 ～ GK3） 1 TXJ/H2BJTU 线束 DG2-H2 1 TXJ/P2BJTU 线束 （SC2 ～ P2） 1 TXJ/P9BJTU 线束 (P9-INLET) 1 TXJ/S1BJTU 线束 S1-SS34 1 TXJ/SJ0QJS 线束 2 TXJ/SPBJTU 线束 (RELAY-SP) 2 TXJD20BJTU 线束 （D20 ～ SC20） 1 TXJD25GLTC 线束 (D25 ～ P25) 1 TXJDG5GLTC 线束 D5-DG5 1 TXJEARBJTU 线束 GND （H-PA） 1 TXJFA1BJTU 线束 (PA31/PA32-FAN) 2 TXJFGNYFSU 线束 (GND-INLET) 1 TXJG51BJTU 线束 H51-G51 1 TXJH40BJTU 线束 H40-PA40 1 TXJP10BJTU 线束 PA10-P10 1 TXJP11BJTU 线束 （P11 ～ SS11） 1 TXJP12BJTU 线束 （P12 ～ SS12） 1 TXJP23BJTU 线束 （P23 ～ SC23） 1 TXJPA2BJTU 线束 PA2-RELAY 1 TXJPA5BJTU 线束 PA5-P5 1 TXJS23BJTU 线束 （SS23 ～ C23） 1 TXN/D1GLTC D 线路板 包装入 1 TXN/G1BJTC G 线路板 完成品 1 TXN/K1BJTC K 线路板 1 TXN/P1GLTC P 线路板 包装入 1 TXN/S1BJTC S 线路板 （半）包装入 1 TXNC11GLTC C1 线路板 包装入 1 TXNC21GLTC C2 线路板 包装入 1 TXNGK1BJTC GK 线路板 完成品 1 TXNPA1BJTC PA 线路板 完成品 1 TXNSC1GLTC SC 线路板 包装入 1 TXNSD1BJTC SD 线路板 包装入 1 TXNSS1GLTC SS 线路板 包装入 1 TXNSU1BJTC SU 线路板 包装入 1 VQLS4199 标签 1 XTB4+12GFJ 螺丝 53 XTB4+12GFJK 螺丝 ( 后盖底部 ) 8 XTB4+16GFJ 螺丝 ( 台架安装块 - 面框 2) 2 XTV3+10JFJK 螺丝 ( 后 AV 端子 6) 4 XTW3+10TFJ 螺丝 3 XYN3+F6FJ 螺丝 1 XYN3+F8FJ 螺丝 30 XYN3+J8FJ 螺丝 8 XYN4+E8FJ 螺丝 1 XYN4+F10FJ 螺丝 6 XYN4+F10FJK 螺丝 6 XYN4+F30FJK 螺丝 6 XYN5+C15FJ 螺丝 ( 台架安装块 8) 8 参考号 部品号 部品名称 & 说明 件数 备注 128 16 电器部件更换清单 16.1. 更换部件清单注意事项 129 16.2. 电器部件更换清单 所有在备注栏 [PPDS] 中提到的部件均由 PPDS 提供。 参考号 部品号 部品名称 & 说明 件数 备注 F401.402 K5D802BNA005 延时保险丝 高 2 C002 ECA1HM100 E 10UF, 50V 1 C003 ECJ1VF1H104Z C 0.1UF, Z, 50V 1 C006 ECA0JM102 E 1000UF, 6.3V 1 C008 ECJ1XF1C104Z C 0.1UF, Z, 16V 1 C009 ECJ1XC1H101J C 100PF, J, 50V 1 C010,11 ECJ1VC1H330J C 33PF, J, 50V 2 C11 K1MN80BA0076 80P 连接接头 1 C12 K1MN30BA0255 30P 连接接头 1 C016 ECJ1XF1C104Z C 0.1UF, Z, 16V 1 C21 K1MN68BA0076 68P 连接接头 1 C22 K1MN30BA0255 30P 连接接头 1 C23 K1KA12BA0107 12P 连接接头 1 C029,30 ECJ1VC1H330J C 33PF, J, 50V 2 C041,42 ECJ1XF1C104Z C 0.1UF, Z, 16V 2 C1100 ECJ0EB1A104K C 0.1UF, K, 10V 1 C1102 ECJ0EB1A104K C 0.1UF, K, 10V 1 C1103 ECJ0EB1E271K C 270PF, K, 25V 1 C1105 ECJ0EB1E271K C 270PF, K, 25V 1 C1106 ECJ1VB1A105K C 0.01UF, Z, 50V 1 C1107 EEEHB0G101R C 100PF, J, 4V 1 C1109-11 ECJ0EB1A104K C 0.1UF, K, 10V 3 C1112 ECJ0EB1E271K C 270PF, K, 25V 1 C1114 ECJ0EB1A104K C 0.1UF, K, 10V 1 C1116 ECJ0EB1A104K C 0.1UF, K, 10V 1 C1118-23 ECJ0EB1A104K C 0.1UF, K, 10V 6 C1125 ECJ0EB1A104K C 0.1UF, K, 10V 1 C1127-32 ECJ0EB1A104K C 0.1UF, K, 10V 6 C1133,34 ECJ1XC1H150J C 15PF, J, 50V 2 C1135-42 ECJ0EB1A104K C 0.1UF, K, 10V 8 C1144-50 ECJ0EB1A104K C 0.1UF, K, 10V 7 C1152 ECJ0EB1A104K C 0.1UF, K, 10V 1 C1153 EEEHB0G101R C 100PF, J, 4V 1 C1154 ECJ0EB1A104K C 0.1UF, K, 10V 1 C1155 ECJ0EB1C103K C 0.010UF, K, 16V 1 C1156,57 ECJ1XC1H220J C 22PF, J, 50V 2 C1158 F1J0J1060004 C 0.010UF, K, 16V 1 C1159 ECJ0EB1A104K C 0.1UF, K, 10V 1 C1160 F2G0J470A019 E 47UF 6.3V 1 C1161 ECJ1VB1A105K C 0.01UF, Z, 50V 1 C1162 ECJ0EB1C103K C 0.010UF, K, 16V 1 C1167,68 ECJ1VB1A105K C 0.01UF, Z, 50V 2 C1172 ECJ0EB1A104K C 0.1UF, K, 10V 1 C1177 ECJ1VB1A334K C 0.1UF, K, 16V 1 C1178 ECJ1VB1A105K C 0.01UF, Z, 50V 1 C1190 ECJ0EB1C103K C 0.010UF, K, 16V 1 C1209 ECJ1VB1A105K C 0.01UF, Z, 50V 1 C1212 ECJ1XC1H151J C 150PF, J, 50V 1 C1219,20 EEEHP1C100R C 10PF, J, 16V 2 C1221 ECJ0EB1H102K C 1000PF, K, 50V 1 C1222,23 F1J0J1060004 C 0.010UF, K, 16V 2 C1226 F1J0J1060004 C 0.010UF, K, 16V 1 C1227 ECJ0EB1H101K C 100PF, K, 50V 1 C1228-34 EEEHB1C470P C 47PF, J, 16V 7 C1294 ECJ1XC1H330J C 33PF, J, 50V 1 C2005,06 ECJ1XC1H561J C 560PF, J, 50V 2 C2010,11 ECJ1XC1H561J C 560PF, J, 50V 2 C2013,14 ECJ1XC1H561J C 560PF, J, 50V 2 C2016,17 ECJ1XC1H561J C 560PF, J, 50V 2 C2019 ECA1CM221 E 220UF, 16V 1 C2020 ECA1HM220 E 22UF, 50V 1 C2021,22 ECJ1XC1H561J C 560PF, J, 50V 2 C2111 ECJ2VF1C104Z C 0.1UF, Z, 16V 1 C2116 ECJ2VF1C104Z C 0.1UF, Z, 16V 1 C2118,19 F2J1C4700003 E 47UF, 16V 2 C2125,26 ECJ1VB1H102K C 1000PF, K, 50V 2 C2127 ECA1CMH101 E 100UF, 16V 1 C2128 ECJ2VF1C104Z C 0.1UF, Z, 16V 1 C2129,30 F1J1A1050002 C 1UF, Z, 50V 2 C2131 ECJ2VF1C104Z C 0.1UF, Z, 16V 1 C2132 EEEHB1C100R C 10PF, J, 16V 1 C2133,34 ECJ1XC1H470J C 47PF, J, 50V 2 C2139-43 ECJ1VB1H103K C 0.001UF, K, 50V 5 C2146 ECJ2VF1C104Z C 0.1UF, Z, 16V 1 C2147 ECA1HM220 E 22UF, 50V 1 C2148-50 ECJ2FB1C105K C 1UF, K, 16V 3 C2152 ECJ2FB1C105K C 1UF, K, 16V 1 C2153 ECJ2FF1C475Z C 0.047UF, Z, 16V 1 C2154 ECJ2VF1C104Z C 0.1UF, Z, 16V 1 C2155 ECJ2FB1C105K C 1UF, K, 16V 1 C2157 ECJ2FB1C105K C 1UF, K, 16V 1 C2159,60 ECJ2FB1C105K C 1UF, K, 16V 2 C2161 ECA1CMH101 E 100UF, 16V 1 C2162-65 ECJ2FB1C105K C 1UF, K, 16V 4 C2168,69 ECJ2FB1C105K C 1UF, K, 16V 2 C2170-72 ECJ1VB1H102K C 1000PF, K, 50V 3 C2173 ECJ1VB1H103K C 0.001UF, K, 50V 1 C2174 ECJ1VB1H102K C 1000PF, K, 50V 1 C2175-77 ECJ1VB1H103K C 0.001UF, K, 50V 3 C2178,79 EEEHB1C100R C 10PF, J, 16V 2 C2181 ECJ2VF1C104Z C 0.1UF, Z, 16V 1 C2183 EEEHB1H3R3R C 3.3PF, J, 50V 1 C2184,85 ECJ2VF1C104Z C 0.1UF, Z, 16V 2 C2189,90 ECJ2FB1C105K C 1UF, K, 16V 2 C2191 ECJ2VF1C104Z C 0.1UF, Z, 16V 1 C2192 EEEHB1C100R C 10PF, J, 16V 1 C2195 ECJ1XC1H470J C 47PF, J, 50V 1 C2196 ECJ2VF1C104Z C 0.1UF, Z, 16V 1 C2197 ECJ2FB0J225K C 2.2UF, Z, 16V 1 C2198 EEEHB0J101P C 100PF, J, 6.3V 1 C2199 ECJ1VC1H560J C 56PF, J, 50V 1 C2200 ECJ1XC1H470J C 47PF, J, 50V 1 C2201 ECJ1XC1H030C C 3PF, C, 50V 1 C2202 ECJ1XC1H050C C 5PF, C, 50V 1 C2203 ECJ1VC1H100C C 10PF, C, 50V 1 C2204 ECJ1XC1H220J C 22PF, J, 50V 1 C2211 ECJ1VB1C104K C 0.1UF, K, 16V 1 C2213 ERJ3GEY0R00 M 0 OHM, 1/16W 1 C2217 F1H0J1050012 C 1UF, K, 16V 1 C2222 ECJ2VF1C104Z C 0.1UF, Z, 16V 1 C2223 ECJ1XC1H390J C 39PF, J, 50V 1 C2225 ECJ2FB1C105K C 1UF, K, 16V 1 C2226 ECJ1VB1H102K C 1000PF, K, 50V 1 C2227 ECA1CMH101 E 100UF, 16V 1 C2228 ECJ1VB1H103K C 0.001UF, K, 50V 1 C2229,30 ECA1CMH101 E 100UF, 16V 2 C2231 ECA1CHG470 E 47UF, 16V 1 C2232 F1H0J1050012 C 1UF, K, 16V 1 C2233,34 ECJ1VB1H102K C 1000PF, K, 50V 2 C2235 F1H0J1050012 C 1UF, K, 16V 1 C2236 ECA1CHG470 E 47UF, 16V 1 C2237-40 ECJ1VB1H103K C 0.001UF, K, 50V 4 C2243 ECA1CHG470 E 47UF, 16V 1 C2301 ECA1EHG471 E 470UF, 25V 1 C2303 ECA1CMH101 E 100UF, 16V 1 C2307 ECA1CMH101 E 100UF, 16V 1 C2314 ECJ1VB1C105K C 0.01UF, K, 16V 1 C2317 ECJ2FB1A105K C 1UF, K, 10V 1 C2320 ECJ2FB1A105K C 1UF, K, 10V 1 C2321 ECJ2XB1H103K C 0.01UF, K, 50V 1 C2322 ECJ2FB1A105K C 1UF, K, 10V 1 C2323,24 ECJ2FB1E224K C 22UF, K, 25V 2 C2325,26 ECJ1VB1E104K C 0.10UF, K, 25V 2 C2327 F1J1H474A757 C 0.47UF, 50V 1 C2328-31 ECJ2FB1E105K C 1UF, K, 25V 4 C2332,33 ECA1EHG471 E 470UF, 25V 2 C2334,35 ECJ1VB1E104K C 0.10UF, K, 25V 2 C2336 F1J1H474A757 C 0.47UF, 50V 1 C2337,38 ECJ2FB1E224K C 22UF, K, 25V 2 C2341 ECJ3YB1E106M C 10 UF, K, 25V 1 C2342 ECJ2FB1E105K C 1UF, K, 25V 1 C2372 ECA1HHG100 E 10UF, 50V 1 C2373 ECJ1VF1H104Z C 0.1UF, Z, 50V 1 C2374 ECJ1VF1A105Z C 1UF, Z, 10V 1 C2380 ECJ1VB1H103K C 0.001UF, K, 50V 1 C2382 ECJ1VB1C105K C 0.01UF, K, 16V 1 参考号 部品号 部品名称 & 说明 件数 备注 130 C2385 ECJ2FB1A105K C 1UF, K, 10V 1 C2387 ECJ2FB1A105K C 1UF, K, 10V 1 C2393,94 ECJ1VB1C105K C 0.01UF, K, 16V 2 C2401 ECJ2FB1A105K C 1UF, K, 10V 1 C2402 ECJ2FB0J106M C 10UF, Z,6.3V 1 C2403 ECJ1VB1H103K C 0.001UF, K, 50V 1 C2417 ECJ2FB0J106M C 10UF, Z,6.3V 1 C2430 ECJ1VF1A105Z C 1UF, Z, 10V 1 C2510,11 ECJ2VF1C105Z C 1UF, Z, 16V 2 C2512 ECJ3XB0J106M C 10UF, M,6.3V 1 C2515 ECJ1VB1H103K C 0.001UF, K, 50V 1 C2521 ECJ1VB1H103K C 0.001UF, K, 50V 1 C3005 ECJ2VF1C104Z C 0.1UF, Z, 16V 1 C3021-25 F1J1A1050002 C 1UF, Z, 50V 5 C3026 ECJ1VB1H103K C 0.001UF, K, 50V 1 C3027,28 F1J1A1050002 C 1UF, Z, 50V 2 C3029 ECJ2VF1C105Z C 1UF, Z, 16V 1 C3030 ECJ2VF1C104Z C 0.1UF, Z, 16V 1 C3031 F1J1A1050002 C 1UF, Z, 50V 1 C3033 F1J1A1050002 C 1UF, Z, 50V 1 C3035 F1J1A1050002 C 1UF, Z, 50V 1 C3036 ECJ1VB1H103K C 0.001UF, K, 50V 1 C3038 ECJ2VF1C104Z C 0.1UF, Z, 16V 1 C3039 ECJ1VB1H103K C 0.001UF, K, 50V 1 C3040 ECJ2VF1C104Z C 0.1UF, Z, 16V 1 C3041 ECJ1VB1H103K C 0.001UF, K, 50V 1 C3043 F1J1A1050002 C 1UF, Z, 50V 1 C3045 F1J1A1050002 C 1UF, Z, 50V 1 C3046 ECJ1VB1H103K C 0.001UF, K, 50V 1 C3047 F1J1A1050002 C 1UF, Z, 50V 1 C3048 ECJ1VB1H103K C 0.001UF, K, 50V 1 C3049,50 F1J1A1050002 C 1UF, Z, 50V 2 C3051-53 ECJ1VB1H103K C 0.001UF, K, 50V 3 C3054-56 F1J1A1050002 C 1UF, Z, 50V 3 C3058 ECA1EM471 E 470UF, 25V 1 C3059,60 ECJ2VF1C105Z C 1UF, Z, 16V 2 C3062-64 ECJ2VF1C104Z C 0.1UF, Z, 16V 3 C3065 ECJ1VB1H103K C 0.001UF, K, 50V 1 C3067 ECJ1VB1H103K C 0.001UF, K, 50V 1 C3069 ECA1EM471 E 470UF, 25V 1 C3070 ECJ2VF1C104Z C 0.1UF, Z, 16V 1 C3075 ECA1CM221 E 220UF, 16V 1 C3207 ECJ2FB1C105K C 1UF, K, 16V 1 C3208 ECJ2FB1C474K C 0.47UF, Z, 16V 1 C3214 ECJ2FF1A106Z C 0.001UF, Z, 10V 1 C3216 ECJ2FF1A106Z C 0.001UF, Z, 10V 1 C3226-28 ECJ2FF1A106Z C 0.001UF, Z, 10V 3 C3230 ECJ2VF1C104Z C 0.1UF, Z, 16V 1 C3233 ECJ2VF1C104Z C 0.1UF, Z, 16V 1 C3241 ECJ2VF1C104Z C 0.1UF, Z, 16V 1 C3248 ECJ2FB1C105K C 1UF, K, 16V 1 C3249 ECJ2FB1C474K C 0.47UF, Z, 16V 1 C3251 ECJ1XF1C104Z C 0.1UF, Z, 16V 1 C3252 ECJ2FB1C105K C 1UF, K, 16V 1 C3253,54 ECJ1XF1C104Z C 0.1UF, Z, 16V 2 C3256 ECJ2FB1C105K C 1UF, K, 16V 1 C3257 ECJ1XF1C104Z C 0.1UF, Z, 16V 1 C3262 ECJ1VB1H472K C 4700PF, K, 50V 1 C3268 ECJ1VB1H103K C 0.001UF, K, 50V 1 C3305 ECJ1XF1C104Z C 0.1UF, Z, 16V 1 C3330 ECA1CM470 E 47UF, 16V 1 C3331 ECJ2XB1H103K C 0.01UF, K, 50V 1 C3332 ECJ2VF1C104Z C 0.1UF, Z, 16V 1 C3334 F2J1C4700003 E 47UF, 16V 1 C3335 ECJ2VB1C104K C 0.1UF, K, 16V 1 C3336 F2J1C4700003 E 47UF, 16V 1 C3337 ECJ2VB1C104K C 0.1UF, K, 16V 1 C3338 F2J1C4700003 E 47UF, 16V 1 C3339 ECJ2VB1C104K C 0.1UF, K, 16V 1 C3340-42 ECJ2VF1C104Z C 0.1UF, Z, 16V 3 C3701 ECJ2XC1H561K C 560PF, K, 50V 1 C3703 ECJ2XC1H561K C 560PF, K, 50V 1 C3711,12 ECJ2VF1H333Z C 0.033UF, Z, 50V 2 C3750,51 ECJ2XC1H102K C 1000PF, K, 50V 2 C4003-08 F1J0J1060004 C 0.010UF, K, 16V 6 C4014,15 F1J0J1060004 C 0.010UF, K, 16V 2 C4023 F1J0J1060004 C 0.010UF, K, 16V 1 参考号 部品号 部品名称 & 说明 件数 备注 C4026 ECJ0EB1A104K C 0.1UF, K, 10V 1 C4027 ECJ1VB1A105K C 0.01UF, Z, 50V 1 C4028 ECJ0EB1C103K C 0.010UF, K, 16V 1 C4112 F1J0J1060004 C 0.010UF, K, 16V 1 C4117 ECJ0EB1A104K C 0.1UF, K, 10V 1 C4158 ECJ1VB1A105K C 0.01UF, Z, 50V 1 C4159 F1H1C104A065 C 0.1UF, K, 16V 1 C4160 ECJ0EB1A104K C 0.1UF, K, 10V 1 C4165 ECJ0EB1A104K C 0.1UF, K, 10V 1 C4168 ECJ1XC1H680J C 68PF, J, 50V 1 C4171 ECJ1XC1H471J C 470PF, J, 50V 1 C4172,73 F1H1C104A065 C 0.1UF, K, 16V 2 C4174 ECJ0EB1A104K C 0.1UF, K, 10V 1 C4175 F1H1C104A065 C 0.1UF, K, 16V 1 C4176 ECJ1VB0J225K C 2.2UF, K, 6.3V 1 C4177 ECJ2FB1C684K C 68UF, Z, 16V 1 C4178 ECJ1XB1C393K C 0.039UF, K, 16V 1 C4180 F1H1C104A065 C 0.1UF, K, 16V 1 C4185,86 ECJ3XB0J106M C 10UF, M,6.3V 2 C4188 F1J0J1060004 C 0.010UF, K, 16V 1 C4189-91 ECJ0EB1A104K C 0.1UF, K, 10V 3 C4193 ECJ0EB1H102K C 1000PF, K, 50V 1 C4194-97 F1H1C104A065 C 0.1UF, K, 16V 4 C4199 ECJ0EB1C103K C 0.010UF, K, 16V 1 C4200 F2G0J470A019 E 47UF 6.3V 1 C4201 ECJ0EB1C103K C 0.010UF, K, 16V 1 C4204 ECJ0EB1A104K C 0.1UF, K, 10V 1 C4205,06 F1H1C104A065 C 0.1UF, K, 16V 2 C4208,09 ECJ0EB1A104K C 0.1UF, K, 10V 2 C4211 ECJ0EB1A104K C 0.1UF, K, 10V 1 C4215 ECJ0EB1A104K C 0.1UF, K, 10V 1 C4216 F2G0J470A019 E 47UF 6.3V 1 C4217 F1H1C104A065 C 0.1UF, K, 16V 1 C4218 ECJ0EB1H102K C 1000PF, K, 50V 1 C4219 ECJ1VB1A105K C 0.01UF, Z, 50V 1 C4224 ECJ0EB1A104K C 0.1UF, K, 10V 1 C4227 ECJ1VB1C823K C 0.082UF, K, 16V 1 C4228 ECJ0EB1C103K C 0.010UF, K, 16V 1 C4235 ECJ0EB1C103K C 0.010UF, K, 16V 1 C4244 ECJ1VB1A105K C 0.01UF, Z, 50V 1 C4245 ECJ0EB1A104K C 0.1UF, K, 10V 1 C4248 ECJ0EB1A104K C 0.1UF, K, 10V 1 C4253 F2G0J470A019 E 47UF 6.3V 1 C4256 ECJ1VB1A105K C 0.01UF, Z, 50V 1 C4262-64 ECJ0EB1A104K C 0.1UF, K, 10V 3 C4266 ECJ0EB1C103K C 0.010UF, K, 16V 1 C4269 ECJ1VB1A105K C 0.01UF, Z, 50V 1 C4272 F2G0J470A019 E 47UF 6.3V 1 C4273 ECJ0EB1A104K C 0.1UF, K, 10V 1 C4281-84 ECJ0EB1A104K C 0.1UF, K, 10V 4 C4287,88 ECJ0EB1A104K C 0.1UF, K, 10V 2 C4289,90 EEEHB0J330R C 33PF, J, 6.3V 2 C4291,92 ECJ0EB1A104K C 0.1UF, K, 10V 2 C4296 F1J0J1060004 C 0.010UF, K, 16V 1 C4297 ECJ0EB1A104K C 0.1UF, K, 10V 1 C4298-06 ECJ1VB1A105K C 0.01UF, Z, 50V 9 C4307-09 ECJ0EB1A104K C 0.1UF, K, 10V 3 C4310 ECJ0EB1C103K C 0.010UF, K, 16V 1 C4311 ECJ0EB1A104K C 0.1UF, K, 10V 1 C4312 ECJ0EB1C103K C 0.010UF, K, 16V 1 C4313,14 ECJ0EB1A104K C 0.1UF, K, 10V 2 C4315 F1J0J1060004 C 0.010UF, K, 16V 1 C4316-18 ECJ0EB1A104K C 0.1UF, K, 10V 3 C4320-22 ECJ0EB1A104K C 0.1UF, K, 10V 3 C4325 ECJ0EB1A104K C 0.1UF, K, 10V 1 C4327 ECJ0EB1A104K C 0.1UF, K, 10V 1 C4329,30 ECJ0EB1A104K C 0.1UF, K, 10V 2 C4331 F1J0J1060004 C 0.010UF, K, 16V 1 C4332 ECJ1VB1A105K C 0.01UF, Z, 50V 1 C4333-38 ECJ0EB1A104K C 0.1UF, K, 10V 6 C4339 ECJ1VB0J225K C 2.2UF, K, 6.3V 1 C4340 ECJ1XC1H471J C 470PF, J, 50V 1 C4341 EEEHB1C470P C 47PF, J, 16V 1 C4342 ECJ0EB1A104K C 0.1UF, K, 10V 1 C4343 EEEHB1C100R C 10PF, J, 16V 1 C4344,45 F1J0J1060004 C 0.010UF, K, 16V 2 C4346 ECJ0EB1A104K C 0.1UF, K, 10V 1 参考号 部品号 部品名称 & 说明 件数 备注 131 C4347 ECJ1VB1A105K C 0.01UF, Z, 50V 1 C4348 EEEHB1C470P C 47PF, J, 16V 1 C4349 ECJ0EB1C103K C 0.010UF, K, 16V 1 C4350,51 ECJ1XC1H181J C 180PF, J, 50V 2 C4352,53 ECJ1XC1H330J C 33PF, J, 50V 2 C4354 ECJ0EB1C103K C 0.010UF, K, 16V 1 C4360 ECJ1VB1A105K C 0.01UF, Z, 50V 1 C4362 F1J0J1060004 C 0.010UF, K, 16V 1 C4363,64 ECJ0EB1A104K C 0.1UF, K, 10V 2 C4365 ECJ1VB1A105K C 0.01UF, Z, 50V 1 C4366 F2G0J470A019 E 47UF 6.3V 1 C4367 ECJ0EB1A104K C 0.1UF, K, 10V 1 C4371 ECJ0EB1H102K C 1000PF, K, 50V 1 C4372 ECJ0EB1A104K C 0.1UF, K, 10V 1 C4373 ECJ1VB1A105K C 0.01UF, Z, 50V 1 C4374 ECJ0EB1A104K C 0.1UF, K, 10V 1 C4375,76 ECJ0EB1H102K C 1000PF, K, 50V 2 C4377 ECJ0EB1A104K C 0.1UF, K, 10V 1 C4379 ECJ0EB1A104K C 0.1UF, K, 10V 1 C4380 ECJ0EB1H102K C 1000PF, K, 50V 1 C4381,82 ECJ0EB1A104K C 0.1UF, K, 10V 2 C4383 ECJ0EB1H102K C 1000PF, K, 50V 1 C4384 ECJ0EB1A104K C 0.1UF, K, 10V 1 C4385 ECJ0EB1H102K C 1000PF, K, 50V 1 C4386 ECJ0EB1A104K C 0.1UF, K, 10V 1 C4387 ECJ0EB1H102K C 1000PF, K, 50V 1 C4388 ECJ1VB1A105K C 0.01UF, Z, 50V 1 C4389 ECJ0EB1A104K C 0.1UF, K, 10V 1 C4390 ECJ0EB1H102K C 1000PF, K, 50V 1 C4391 ECJ1VB1A105K C 0.01UF, Z, 50V 1 C4392 ECJ0EB1A104K C 0.1UF, K, 10V 1 C4393,94 ECJ0EB1H102K C 1000PF, K, 50V 2 C4395 ECJ0EB1A104K C 0.1UF, K, 10V 1 C4396 ECJ0EB1H102K C 1000PF, K, 50V 1 C4397,98 ECJ0EB1A104K C 0.1UF, K, 10V 2 C4399,00 ECJ1VB1A105K C 0.01UF, Z, 50V 2 C4401 ECJ0EB1A104K C 0.1UF, K, 10V 1 C4402,03 ECJ0EB1H102K C 1000PF, K, 50V 2 C4404 ECJ0EB1A104K C 0.1UF, K, 10V 1 C4405 ECJ1VB1A105K C 0.01UF, Z, 50V 1 C4406 ECJ0EB1H102K C 1000PF, K, 50V 1 C4407,08 ECJ0EB1A104K C 0.1UF, K, 10V 2 C4409 ECJ0EB1H102K C 1000PF, K, 50V 1 C4410 ECJ1VB1A105K C 0.01UF, Z, 50V 1 C4411,12 ECJ0EB1A104K C 0.1UF, K, 10V 2 C4413,14 ECJ0EB1H102K C 1000PF, K, 50V 2 C4415 ECJ0EB1A104K C 0.1UF, K, 10V 1 C4417 F2G0J470A019 E 47UF 6.3V 1 C4418,19 ECJ1VB1A105K C 0.01UF, Z, 50V 2 C4420,21 ECJ0EB1A104K C 0.1UF, K, 10V 2 C4422-24 ECJ0EB1H102K C 1000PF, K, 50V 3 C4425,26 ECJ0EB1A104K C 0.1UF, K, 10V 2 C4427 ECJ0EB1H102K C 1000PF, K, 50V 1 C4428 ECJ0EB1A104K C 0.1UF, K, 10V 1 C4429,30 ECJ0EB1H102K C 1000PF, K, 50V 2 C4434 ECJ0EB1H102K C 1000PF, K, 50V 1 C4435 ECJ1VB1A105K C 0.01UF, Z, 50V 1 C4436-39 ECJ0EB1H102K C 1000PF, K, 50V 4 C4440 ECJ0EB1A104K C 0.1UF, K, 10V 1 C4441,42 ECJ0EB1H102K C 1000PF, K, 50V 2 C4447 ECJ1VB1A105K C 0.01UF, Z, 50V 1 C4448 ECJ0EB1C103K C 0.010UF, K, 16V 1 C4451 ECJ0EB1H102K C 1000PF, K, 50V 1 C4452 ECJ0EB1A104K C 0.1UF, K, 10V 1 C4453,54 ECJ0EB1H102K C 1000PF, K, 50V 2 C4455 ECJ1VB1A105K C 0.01UF, Z, 50V 1 C4456 ECJ0EB1A104K C 0.1UF, K, 10V 1 C4457,58 ECJ0EB1H102K C 1000PF, K, 50V 2 C4459 ECJ0EB1A104K C 0.1UF, K, 10V 1 C4460 ECJ0EB1H102K C 1000PF, K, 50V 1 C4461 ECJ1XC1H820J C 82PF, J, 50V 1 C4462 ECJ0EB1A104K C 0.1UF, K, 10V 1 C4464 ECJ1VB1A105K C 0.01UF, Z, 50V 1 C4465 ECJ0EB1A104K C 0.1UF, K, 10V 1 C4466 ECJ0EB1C103K C 0.010UF, K, 16V 1 C4467 ECJ0EB1A104K C 0.1UF, K, 10V 1 C4470 ECJ1VB1A105K C 0.01UF, Z, 50V 1 参考号 部品号 部品名称 & 说明 件数 备注 C4474 ECJ1VB1A105K C 0.01UF, Z, 50V 1 C4475,76 ECJ0EB1H102K C 1000PF, K, 50V 2 C4477 ECJ0EB1A104K C 0.1UF, K, 10V 1 C4478 ECJ1VB1A105K C 0.01UF, Z, 50V 1 C4479-81 ECJ0EB1H102K C 1000PF, K, 50V 3 C4482 ECJ1XC1H180J C 18PF, J, 50V 1 C4483 ECJ1XC1H150J C 15PF, J, 50V 1 C4493 ECJ0EB1A104K C 0.1UF, K, 10V 1 C4494 ECJ1VB1A105K C 0.01UF, Z, 50V 1 C4496 ECJ0EB1A104K C 0.1UF, K, 10V 1 C4497 EEEHB0G101R C 100PF, J, 4V 1 C4498 ECJ1XC1H471J C 470PF, J, 50V 1 C4499 EEFCD0G560ER 56UF, 1 C4501 ECJ0EB1A104K C 0.1UF, K, 10V 1 C4502 ECJ0EB1C103K C 0.010UF, K, 16V 1 C4503 ECJ0EB1A104K C 0.1UF, K, 10V 1 C4504 ECJ0EB1C103K C 0.010UF, K, 16V 1 C4505 ECJ0EB1A104K C 0.1UF, K, 10V 1 C4506 ECJ0EB1C103K C 0.010UF, K, 16V 1 C4507 ECJ0EB1A104K C 0.1UF, K, 10V 1 C4508 ECJ0EB1C103K C 0.010UF, K, 16V 1 C4509-11 ECJ0EB1A104K C 0.1UF, K, 10V 3 C4512 ECJ0EB1C103K C 0.010UF, K, 16V 1 C4513 ECJ0EB1A104K C 0.1UF, K, 10V 1 C4514 ECJ0EB1C103K C 0.010UF, K, 16V 1 C4515,16 ECJ0EB1A104K C 0.1UF, K, 10V 2 C4517 ECJ0EB1C103K C 0.010UF, K, 16V 1 C4518 ECJ0EB1A104K C 0.1UF, K, 10V 1 C4519 ECJ0EB1C103K C 0.010UF, K, 16V 1 C4520 ECJ0EB1A104K C 0.1UF, K, 10V 1 C4521 ECJ0EB1C103K C 0.010UF, K, 16V 1 C4522 ECJ0EB1A104K C 0.1UF, K, 10V 1 C4523 ECJ0EB1C103K C 0.010UF, K, 16V 1 C4524 ECJ0EB1A104K C 0.1UF, K, 10V 1 C4525 ECJ0EB1C103K C 0.010UF, K, 16V 1 C4526 ECJ0EB1A104K C 0.1UF, K, 10V 1 C4527 ECJ0EB1C103K C 0.010UF, K, 16V 1 C4528 F2G0J470A019 E 47UF 6.3V 1 C4529 ECJ0EB1A104K C 0.1UF, K, 10V 1 C4530,31 ECJ0EB1H102K C 1000PF, K, 50V 2 C4532,33 ECJ0EB1A104K C 0.1UF, K, 10V 2 C4534 ECJ0EB1H102K C 1000PF, K, 50V 1 C4535 ECJ0EB1A104K C 0.1UF, K, 10V 1 C4536 ECJ1VB1A105K C 0.01UF, Z, 50V 1 C4537 EEEHB0G101R C 100PF, J, 4V 1 C4538 ECJ0EB1A104K C 0.1UF, K, 10V 1 C4539 ECJ1VB1A105K C 0.01UF, Z, 50V 1 C4540 ECJ0EB1H102K C 1000PF, K, 50V 1 C4541 ECJ0EB1A104K C 0.1UF, K, 10V 1 C4543 F1H1C104A065 C 0.1UF, K, 16V 1 C4544 ECJ1VB1C105K C 0.01UF, K, 16V 1 C5604 ECA1HHG100 E 10UF, 50V 1 C5605 EEUFC1E471 E 470UF, 25V 1 C5606 ECA1CM471 E 470UF, 16V 1 C5609 ECA1HM220 E 22UF, 50V 1 C5611 F2A1H331A257 E 330UF, 50V 1 C5612 ECA1CM471 E 470UF, 16V 1 C5613 ECJ1VB1E104K C 0.10UF, K, 25V 1 C5616 ECJ1VB1E104K C 0.10UF, K, 25V 1 C5617 ECA1CM471 E 470UF, 16V 1 C5618,19 ECJ1VB1E104K C 0.10UF, K, 25V 2 C5622 ECA1CM471 E 470UF, 16V 1 C5623 ECJ1VB1E104K C 0.10UF, K, 25V 1 C5626 ECJ1XF1C104Z C 0.1UF, Z, 16V 1 C5633 ECA1EM221 E 220UF, 25V 1 C5637 ECJ1XF1C104Z C 0.1UF, Z, 16V 1 C5641-44 ECJ1XF1C104Z C 0.1UF, Z, 16V 4 C5645 ECA1CHG470 E 47UF, 16V 1 C5646 ECJ1VB1H103K C 0.001UF, K, 50V 1 C5647 ECA1CHG470 E 47UF, 16V 1 C5648 ECJ1VB1H103K C 0.001UF, K, 50V 1 C5670 ECJ1VB1E104K C 0.10UF, K, 25V 1 C5672 ECA1HHG100 E 10UF, 50V 1 C5673 ECJ1XF1C104Z C 0.1UF, Z, 16V 1 C5685 ECA1HHG100 E 10UF, 50V 1 C5686 ECJ2XB1H103K C 0.01UF, K, 50V 1 C5801,02 EEUFC1E471 E 470UF, 25V 2 参考号 部品号 部品名称 & 说明 件数 备注 132 C5804 ECJ1XF1C104Z C 0.1UF, Z, 16V 1 C5805 ECJ2VF1C105Z C 1UF, Z, 16V 1 C5809 ECJ3XF1E105Z C 1UF, Z, 25V 1 C5810 ECA1EHG470 E 47UF, 25V 1 C6001 F1L2J332A022 C 3300UF, K,6.3V 1 C6002 F1L2J222A022 C 2200UF, K,6.3V 1 C6011-15 F2A2T201A001 E 200UF, 5 C6021,22 F1L2J272A022 C 2700UF, K,6.3V 2 C6031 ECQE2255JF P 2.5UF, K,250V 1 C6041-44 TCUY1C105ZFN C 1UF, 16V 4 C6091 F1L2J1020001 C 1000UF, K,6.3V 1 C6111,12 F2A2D221A022 E 220UF, 200V 2 C6132 F1L1E4750004 C 4.7UF, 25V 1 C6134,35 F1L1E4750004 C 4.7UF, 25V 2 C6151 ECJ3YB1E105K C 1UF, K, 25V 1 C6152-55 F1L1E4750004 C 4.7UF, 25V 4 C6192 ECJ3YB1E105K C 1UF, K, 25V 1 C6194,95 F1L1E4750004 C 4.7UF, 25V 2 C6201,02 F0C2E405A176 E 0.040UF, 250V 2 C6211,12 F1L1E4750004 C 4.7UF, 25V 2 C6213,14 ECA1EM471 E 470UF, 25V 2 C6221 ECJ2XB1H104K C 0.1UF, K, 50V 1 C6241 ECA1EM471 E 470UF, 25V 1 C6242 TCUY1C105ZFN C 1UF, 16V 1 C6243 ECJ2XB1H103K C 0.01UF, K, 50V 1 C6251 TCUY1C105ZFN C 1UF, 16V 1 C6261,62 F2A2A221A073 E 220UF, 100V 2 C6271 ECJ3YB1E105K C 1UF, K, 25V 1 C6272,73 EEUFC1E221 E 220UF, 25V 2 C6401 F1L2J332A022 C 3300UF, K,6.3V 1 C6402 F1L2J222A022 C 2200UF, K,6.3V 1 C6411-15 F2A2T201A001 E 200UF, 5 C6421,22 F1L2J272A022 C 2700UF, K,6.3V 2 C6431 F0C2E405A176 E 0.040UF, 250V 1 C6472 ECJ2XB1H104K C 0.1UF, K, 50V 1 C6480 ECJ2XB1H104K C 0.1UF, K, 50V 1 C6502 F1L1E4750004 C 4.7UF, 25V 1 C6504,05 F1L1E4750004 C 4.7UF, 25V 2 C6511,12 F0C2E405A176 E 0.040UF, 250V 2 C6521 ECJ3YB1E105K C 1UF, K, 25V 1 C6522 F1L1E4750004 C 4.7UF, 25V 1 C6524,25 F1L1E4750004 C 4.7UF, 25V 2 C6527 F1L1E4750004 C 4.7UF, 25V 1 C6561 F2A1A1010074 E 100UF, 10V 1 C6563 F2A1A1010074 E 100UF, 10V 1 C6565,66 ECJ2XB1H103K C 0.01UF, K, 50V 2 C6581 ECJ3YB1E105K C 1UF, K, 25V 1 C6582 TCUY1C105ZFN C 1UF, 16V 1 C6591 ECJ3YB1E105K C 1UF, K, 25V 1 C6592 ECA1EM471 E 470UF, 25V 1 C6593 ECJ2XC1H102J C 1000PF, J, 50V 1 C6601,02 F1L1E4750004 C 4.7UF, 25V 2 C6603 F1K2J102A014 C 1000UF, K,6.3V 1 C6604 F2A2V470A020 E 47UF, 350V 1 C6605 ECJ2XB1H104K C 0.1UF, K, 50V 1 C6606 F1K2J102A014 C 1000UF, K,6.3V 1 C6610 ECJ3YB1E105K C 1UF, K, 25V 1 C6611 ECJ2XB1H103K C 0.01UF, K, 50V 1 C6612 ECJ3YB1E105K C 1UF, K, 25V 1 C6620 ECJ3XB2J222K C 2200PF, K,630V 1 C6641 ECQE2224KF P 2.2UF, K,250V 1 C6661,62 F1K2J102A014 C 1000UF, K,6.3V 2 C6671 F1L1E4750004 C 4.7UF, 25V 1 C6681,82 F1L1E4750004 C 4.7UF, 25V 2 C6683 ECJ2XB1H104K C 0.1UF, K, 50V 1 C6691 ECA2CM101 E 100UF, 160V 1 C6701-08 ECJ2XB1H104K C 0.1UF, K, 50V 8 C6721 ECA1HM101 E 100UF, 50V 1 C6723-25 F1L1E4750004 C 4.7UF, 25V 3 C6726,27 TCUY1C105ZFN C 1UF, 16V 2 C6728 ECJ2XC1H102J C 1000PF, J, 50V 1 C6752 TCUY1C105ZFN C 1UF, 16V 1 C6753 F1L1E4750004 C 4.7UF, 25V 1 C6754 ECA1VM470 E 47UF, 35V 1 C6755 ECJ2XB1H104K C 0.1UF, K, 50V 1 C6771 TCUY1C105ZFN C 1UF, 16V 1 C6772,73 F1L1E4750004 C 4.7UF, 25V 2 参考号 部品号 部品名称 & 说明 件数 备注 C6775 F1L1E4750004 C 4.7UF, 25V 1 C6776,77 ECJ2XB1H104K C 0.1UF, K, 50V 2 C6791 EEUFC1E221 E 220UF, 25V 1 C6795,96 EEUFC1E221 E 220UF, 25V 2 C6802 EEUFC1E221 E 220UF, 25V 1 C6803 ECJ2XB1H104K C 0.1UF, K, 50V 1 C6804 F2A2E100A022 E 10UF, 250V 1 C6805 TCUY1C105ZFN C 1UF, 16V 1 C6806,07 ECA2CM101 E 100UF, 160V 2 C6811 ECJ2XB1H103K C 0.01UF, K, 50V 1 C6812 ECJ3YB1E105K C 1UF, K, 25V 1 C6822 F2A2V100A019 E 10UF, 350V 1 C6823 ECJ2XB1H103K C 0.01UF, K, 50V 1 C6841,42 ECA2CM101 E 100UF, 160V 2 C6845 ECJ2XB1H103K C 0.01UF, K, 50V 1 C6861 TCUY1C105ZFN C 1UF, 16V 1 C6862 ECJ3YB1E105K C 1UF, K, 25V 1 C6863 ECJ2XB1H103K C 0.01UF, K, 50V 1 C6871 TCUY1C105ZFN C 1UF, 16V 1 C6872 ECJ3YB1E105K C 1UF, K, 25V 1 C6873 ECJ2XB1H103K C 0.01UF, K, 50V 1 C6901 ECJ2XB1H102K C 1000PF, K, 50V 1 C6902 TCUY1C105ZFN C 1UF, 16V 1 C6904 TCUY1C105ZFN C 1UF, 16V 1 C6906 TCUY1C105ZFN C 1UF, 16V 1 C6908 TCUY1C105ZFN C 1UF, 16V 1 C6910 TCUY1C105ZFN C 1UF, 16V 1 C6912 TCUY1C105ZFN C 1UF, 16V 1 C6914-18 ECJ2XB1H221K C 220PF, K, 50V 5 C6931 ECJ2XB1H102K C 1000PF, K, 50V 1 C6932-35 F1L2E105A013 E 0.10UF, 25V 4 C6951 ECJ2XB1H102K C 1000PF, K, 50V 1 C6952 TCUY1C105ZFN C 1UF, 16V 1 C6955 TCUY1C105ZFN C 1UF, 16V 1 C6957,58 TCUY1C105ZFN C 1UF, 16V 2 C6961 TCUY1C105ZFN C 1UF, 16V 1 C6963 TCUY1C105ZFN C 1UF, 16V 1 C6964-68 ECJ2XB1H221K C 220PF, K, 50V 5 C6981 ECJ2XB1H102K C 1000PF, K, 50V 1 C6982-85 F1L2E105A013 E 0.10UF, 25V 4 C7103 ECJ3XB2A474K C 0.47UF, 6.3V 1 C7104,05 TCUY1C105ZFN C 1UF, 16V 2 C7106 ECJ3XB2A474K C 0.47UF, 6.3V 1 C7107 ECJ1XC1H101J C 100PF, J, 50V 1 C7110 ECJ1XC1H101J C 100PF, J, 50V 1 C7111 ECJ3XB2A474K C 0.47UF, 6.3V 1 C7112,13 TCUY1C105ZFN C 1UF, 16V 2 C7114 ECJ3XB2A474K C 0.47UF, 6.3V 1 C7115 ECJ1XC1H101J C 100PF, J, 50V 1 C7118 ECJ3XB2A474K C 0.47UF, 6.3V 1 C7119 TCUY1C105ZFN C 1UF, 16V 1 C7120 ECJ1XC1H101J C 100PF, J, 50V 1 C7121 TCUY1C105ZFN C 1UF, 16V 1 C7122 ECJ3XB2A474K C 0.47UF, 6.3V 1 C7123,24 ECJ1XC1H101J C 100PF, J, 50V 2 C7125 ECJ3XB2A474K C 0.47UF, 6.3V 1 C7126,27 TCUY1C105ZFN C 1UF, 16V 2 C7128,29 ECJ3XB2A474K C 0.47UF, 6.3V 2 C7130,31 TCUY1C105ZFN C 1UF, 16V 2 C7132,33 ECJ3XB2A474K C 0.47UF, 6.3V 2 C7134,35 TCUY1C105ZFN C 1UF, 16V 2 C7136 ECJ3XB2A474K C 0.47UF, 6.3V 1 C7144 ECJ1XB1C104K C 0.1UF, Z, 16V 1 C7146 ECJ1XB1C104K C 0.1UF, Z, 16V 1 C7148 ECJ1XB1C104K C 0.1UF, Z, 16V 1 C7150 ECJ1XB1C104K C 0.1UF, Z, 16V 1 C7152 ECJ1XB1C104K C 0.1UF, Z, 16V 1 C7154 ECJ1XB1C104K C 0.1UF, Z, 16V 1 C7156 ECJ1XB1C104K C 0.1UF, Z, 16V 1 C7158 ECJ1XB1C104K C 0.1UF, Z, 16V 1 C7161,62 ECJ3XB2A474K C 0.47UF, 6.3V 2 C7203 ECJ3XB2A474K C 0.47UF, 6.3V 1 C7204,05 TCUY1C105ZFN C 1UF, 16V 2 C7206 ECJ3XB2A474K C 0.47UF, 6.3V 1 C7207 ECJ1XC1H101J C 100PF, J, 50V 1 C7211 ECJ3XB2A474K C 0.47UF, 6.3V 1 C7212,13 TCUY1C105ZFN C 1UF, 16V 2 参考号 部品号 部品名称 & 说明 件数 备注 133 C7214 ECJ3XB2A474K C 0.47UF, 6.3V 1 C7215 ECJ1XC1H101J C 100PF, J, 50V 1 C7219 ECJ3XB2A474K C 0.47UF, 6.3V 1 C7220,21 TCUY1C105ZFN C 1UF, 16V 2 C7222 ECJ3XB2A474K C 0.47UF, 6.3V 1 C7223 ECJ1XC1H101J C 100PF, J, 50V 1 C7227 ECJ3XB2A474K C 0.47UF, 6.3V 1 C7228,29 TCUY1C105ZFN C 1UF, 16V 2 C7230 ECJ3XB2A474K C 0.47UF, 6.3V 1 C7231 ECJ1XC1H101J C 100PF, J, 50V 1 C7234 ECJ1XB1C104K C 0.1UF, Z, 16V 1 C7236 ECJ1XB1C104K C 0.1UF, Z, 16V 1 C7238 ECJ1XB1C104K C 0.1UF, Z, 16V 1 C7240 ECJ1XB1C104K C 0.1UF, Z, 16V 1 C7242 ECJ1XB1C104K C 0.1UF, Z, 16V 1 C7243 ECJ1XC1H101J C 100PF, J, 50V 1 C7247 ECJ3XB2A474K C 0.47UF, 6.3V 1 C7248,49 TCUY1C105ZFN C 1UF, 16V 2 C7250 ECJ3XB2A474K C 0.47UF, 6.3V 1 C7251 ECJ1XB1C104K C 0.1UF, Z, 16V 1 C7256,57 ECJ3XB2A474K C 0.47UF, 6.3V 2 C9028,29 F1J0J1060004 C 0.010UF, K, 16V 2 C9033,34 ECJ1XF1C104Z C 0.1UF, Z, 16V 2 C9035,36 F1J0J1060004 C 0.010UF, K, 16V 2 C9037 ECJ1VB1H103K C 0.001UF, K, 50V 1 C9039 F1J0J1060004 C 0.010UF, K, 16V 1 C9040 ECJ1XF1C104Z C 0.1UF, Z, 16V 1 C9044-53 ECJ1XF1C104Z C 0.1UF, Z, 16V 10 C9055-57 ECJ1XF1C104Z C 0.1UF, Z, 16V 3 C9058 F1J0J1060004 C 0.010UF, K, 16V 1 C9300-25 ECJ1XB1C104K C 0.1UF, Z, 16V 26 C9327-51 ECJ1XB1C104K C 0.1UF, Z, 16V 25 C9352 EEFCD0G560ER 56UF, 1 C9355-59 ECJ1XB1C104K C 0.1UF, Z, 16V 5 C9360-64 ECJ3XB0J106M C 10UF, M,6.3V 5 C9365 EEFCD0G560ER 56UF, 1 C9368 ECJ1XB1C104K C 0.1UF, Z, 16V 1 C9442-70 ECJ1XB1C104K C 0.1UF, Z, 16V 29 C9472-96 ECJ1XB1C104K C 0.1UF, Z, 16V 25 C9497 EEFCD0G560ER 56UF, 1 C9512,13 ECJ1XB1C104K C 0.1UF, Z, 16V 2 C9514 ECJ2VF1C105Z C 1UF, Z, 16V 1 C9516-25 ECJ1XB1C104K C 0.1UF, Z, 16V 10 C9526 F1J0J1060004 C 0.010UF, K, 16V 1 C9527-30 ECJ1XB1C104K C 0.1UF, Z, 16V 4 C9531 F1J0J1060004 C 0.010UF, K, 16V 1 C9532 ECJ1XC1H101K C 100PF, K, 50V 1 C9533 ECJ1XB1C104K C 0.1UF, Z, 16V 1 C9534-38 ECJ3XB0J106M C 10UF, M,6.3V 5 C9539 EEFCD0G560ER 56UF, 1 C9540,41 ECJ1VF1H103Z C 0.010UF, Z, 50V 2 C9542 ECJ1XB1C104K C 0.1UF, Z, 16V 1 C9546,47 ECJ1VC1H120J C 12PF, J, 50V 2 C9548 ECJ1XB1C104K C 0.1UF, Z, 16V 1 C9552 ECJ1XB1C104K C 0.1UF, Z, 16V 1 C9554 F1J0J1060004 C 0.010UF, K, 16V 1 C9557 ECJ2VF1C105Z C 1UF, Z, 16V 1 C9601 ECJ1XF1C104Z C 0.1UF, Z, 16V 1 C9608 ECJ1XF1C104Z C 0.1UF, Z, 16V 1 C9800 ECJ1XB1C104K C 0.1UF, Z, 16V 1 C9801 ECJ1VB1H472K C 4700PF, K, 50V 1 C9802 ECJ1XC1H470J C 47PF, J, 50V 1 C9803 ECJ1VB1H472K C 4700PF, K, 50V 1 C9804 ECJ1XB1C104K C 0.1UF, Z, 16V 1 C9805 ECJ1VB0J475K C 4.7UF, K, 6.3V 1 C9806 ECGRL0G680ER C 68PF, J, 4V 1 C9807,08 ECJ3YB1E106M C 10 UF, K, 25V 2 C9809 ECJ1XB1C104K C 0.1UF, Z, 16V 1 C9815,16 ECGRL0G680ER C 68PF, J, 4V 2 C9817,18 ECJ3YB1E106M C 10 UF, K, 25V 2 C9822 F1J0J1060004 C 0.010UF, K, 16V 1 C9823,24 ECJ3YB1E106M C 10 UF, K, 25V 2 C9825 ECJ1XC1H101K C 100PF, K, 50V 1 C9826 ECJ1XF1C104Z C 0.1UF, Z, 16V 1 C9827 F1J0J1060004 C 0.010UF, K, 16V 1 C9830-32 ECJ3XB1C106M C 1.0UF, K, 16V 3 C9833 ECJ3YB1E106M C 10 UF, K, 25V 1 参考号 部品号 部品名称 & 说明 件数 备注 C9837 ECJ3XB1C106M C 1.0UF, K, 16V 1 C9838 ECJ1XF1C104Z C 0.1UF, Z, 16V 1 C9840 ECJ1XF1C104Z C 0.1UF, Z, 16V 1 C9841,42 ECJ2VF1C105Z C 1UF, Z, 16V 2 C9843 ECJ1XF1C104Z C 0.1UF, Z, 16V 1 C9844 ECJ1VF1H103Z C 0.010UF, Z, 50V 1 C9845,46 ECJ1XF1C104Z C 0.1UF, Z, 16V 2 C9847,48 ECJ1VB1E104K C 0.10UF, K, 25V 2 C9880,81 ECJ1XB1H102K C 1000UF, Z, 50V 2 C9882 ECJ1XB1C104K C 0.1UF, Z, 16V 1 C9883 ECJ1VB1H822K C 8200PF, K, 50V 1 C9884 ECJ1VC1H100C C 10PF, C, 50V 1 C9885 ECJ1XB1H102K C 1000UF, Z, 50V 1 C9886 ECJ1XB1C104K C 0.1UF, Z, 16V 1 C9887 ECJ1VB0J475K C 4.7UF, K, 6.3V 1 C9891 ECJ1XB1C104K C 0.1UF, Z, 16V 1 C9896 ECJ1XB1C104K C 0.1UF, Z, 16V 1 C9897 ECJ1VB1H822K C 8200PF, K, 50V 1 C9898 ECJ1VC1H100C C 10PF, C, 50V 1 C9899 ECJ1XB1H102K C 1000UF, Z, 50V 1 C9926 ECJ1XB1C104K C 0.1UF, Z, 16V 1 C9967 ECJ1VB0J475K C 4.7UF, K, 6.3V 1 C9971 ECJ1XB1C104K C 0.1UF, Z, 16V 1 CB1-11 K1MN68BA0002 68P 连接接头 11 D3 K1KY40B00003 40P 连接接头 1 D5 K1KB31BA0064 31P 连接接头 1 D6 K1KA21A00011 21P 连接接头 1 D20 K1KA20BA0296 20P 连接接头 1 D25 K1KA20AA0009 20P 连接接头 1 D33 K1MN68BA0076 68P 连接接头 1 D34 K1MN80BA0076 80P 连接接头 1 D1106,07 MA729 二极管 2 D1117 MA3036L 稳压二极管 1 D1119 MA704A 二极管 1 D1121 MA729 二极管 1 D2011-14 MA111 二极管 4 D2119 B0BC01100001 稳压二极管 1 D2300,01 MA111 二极管 2 D2303,04 MA111 二极管 2 D2309 MA111 二极管 1 D2510,11 MA8056-M 稳压二极管 2 D2512 MA8043LTX 稳压二极管 1 D2520 LNJ107W5PRW LED 1 D2524 MA8056-M 稳压二极管 1 D3003 MA8140M 稳压二极管 1 D3005,06 MA8140M 稳压二极管 2 D3017 MA8140M 稳压二极管 1 D3021-23 MA111 二极管 3 D3024 B0BC01100001 稳压二极管 1 D3038-43 MA8140M 稳压二极管 6 D3044 MA111 二极管 1 D3045-52 MA8140M 稳压二极管 8 D3100 MA8140M 稳压二极管 1 D3334-39 MA111 二极管 6 D3702 MA8140M 稳压二极管 1 D4019-38 EZJZ0V80008B 变压器 20 D4041 EZJZ0V80008B 变压器 1 D4044,45 EZJZ0V80008B 变压器 2 D4047,48 MA3056M 稳压二极管 2 D4049-52 B0HCMM000014 二极管 4 D5606 B0BC01100001 稳压二极管 1 D5607 B0BC6R600005 稳压二极管 1 D5610 B0BC4R700007 稳压二极管 1 PA D5610 MA3X78900L 稳压二极管 1 H D5612 B0BC3R700006 稳压二极管 1 D5618 B0BC03900015 稳压二极管 1 D5634 MA111 二极管 1 D5635 MA3047H 稳压二极管 1 D5637,38 MA152 二极管 2 D5639 MA3047H 稳压二极管 1 D5640 MA3039H 稳压二极管 1 D5641 MA152 二极管 1 D5642 MA3120M 稳压二极管 1 D5643 MA152 二极管 1 D5644 MA3068M 稳压二极管 1 参考号 部品号 部品名称 & 说明 件数 备注 134 D5646,47 MA152 二极管 2 D5649 MA111 二极管 1 D5801 B0JCME000037 二极管 1 D5804 MA3120M 稳压二极管 1 D5805,06 MA152 二极管 2 D5807 MA111 二极管 1 D6001 B0HBSN000008 二极管 1 D6021 B0HBSN000008 二极管 1 D6032 MA111 二极管 1 D6041 B0ECHP000003 二极管 1 D6051 B0ECHP000003 二极管 1 D6061,62 B0HBSN000008 二极管 2 D6071,72 MA3DF30000LZ 稳压二极管 2 D6081,82 B0HBSN000008 二极管 2 D6091 MA3DF30000LZ 稳压二极管 1 D6092 B0ECHP000003 二极管 1 D6101-04 B0JCME000037 二极管 4 D6131,32 B0ECHP000003 二极管 2 D6151-54 B0ECHP000003 二极管 4 D6191-93 B0ECHP000003 二极管 3 D6211 B0JCME000037 二极管 1 D6221 B0ECHP000003 二极管 1 D6222,23 MA111 二极管 2 D6251,52 MA8330M 稳压二极管 2 D6253 LNJ301MPUJA LED 1 D6254 MA8051L 稳压二极管 1 D6255 MA111 二极管 1 D6401,02 B0HBSN000008 二极管 2 D6431,32 MA3DF40000LZ 二极管 2 D6441 B0ECHP000003 二极管 1 D6451 B0ECHP000003 二极管 1 D6461,62 B0HBSN000008 二极管 2 D6466 MA111 二极管 1 D6471 MA3DF30000LZ 稳压二极管 1 D6472 B0ECHP000003 二极管 1 D6477 MA111 二极管 1 D6478 B0HCKS000002 二极管 1 D6480 MA111 二极管 1 D6481,82 B0HBSN000008 二极管 2 D6491 MA3DF40000LZ 二极管 1 D6497 MA111 二极管 1 D6501,02 B0ECHP000003 二极管 2 D6521-24 B0ECHP000003 二极管 4 D6581,82 MA8330M 稳压二极管 2 D6583 LNJ301MPUJA LED 1 D6584 MA8051L 稳压二极管 1 D6585 MA111 二极管 1 D6601 MA8240M 稳压二极管 1 D6602 B0ECHP000003 二极管 1 D6603 MA8240M 稳压二极管 1 D6604 MA111 二极管 1 D6605 MA8051L 稳压二极管 1 D6606 B0HCMM000014 二极管 1 D6607 MA111 二极管 1 D6610 MAZ81500ML 稳压二极管 1 D6611-14 MA111 二极管 4 D6619,20 B0HCKS000002 二极管 2 D6621 B0HDSM000005 二极管 1 D6623,24 B0HDSM000005 二极管 2 D6641,42 B0HCKS000002 二极管 2 D6643 MA111 二极管 1 D6644 B0HCKS000002 二极管 1 D6661 MA111 二极管 1 D6662-64 MA8330M 稳压二极管 3 D6665 MA8051L 稳压二极管 1 D6666,67 MA111 二极管 2 D6671 MA111 二极管 1 D6682 B0HCMM000014 二极管 1 D6683,84 MA111 二极管 2 D6686,87 MA111 二极管 2 D6701,02 MA8056H 稳压二极管 2 D6721 B0HCKS000002 二极管 1 D6723,24 B0JCME000037 二极管 2 D6725 B0ECHP000003 二极管 1 D6726-33 MA8056H 稳压二极管 8 D6734 MA111 二极管 1 D6752 B0JCME000037 二极管 1 参考号 部品号 部品名称 & 说明 件数 备注 D6758 B0ECHP000003 二极管 1 D6760,61 MA111 二极管 2 D6771 B0JCME000037 二极管 1 D6773 B0HCKS000002 二极管 1 D6791 MA8200M 稳压二极管 1 D6801,02 B0JCME000037 二极管 2 D6803 MA111 二极管 1 D6804 B0ECHP000003 二极管 1 D6805 MA111 二极管 1 D6806 B0ECHP000003 二极管 1 D6820-23 MA111 二极管 4 D6825 MA8330M 稳压二极管 1 D6826 MA111 二极管 1 D6841 B0ECHP000003 二极管 1 D6842,43 MA111 二极管 2 D6859 B0ECHP000003 二极管 1 D6860 B0HCKS000002 二极管 1 D6861 MA8051L 稳压二极管 1 D6862 MA111 二极管 1 D6871 MA8051L 稳压二极管 1 D6872 MA111 二极管 1 D6901,02 MA8056H 稳压二极管 2 D6903,04 B0ECHP000003 二极管 2 D6951,52 MA8056H 稳压二极管 2 D6953,54 B0ECHP000003 二极管 2 D9017-19 MA3033 稳压二极管 3 D9020 MA728 二极管 1 D9035 MA728 二极管 1 D9100-03 B0JCGD000002 二极管 4 D9105,06 B0JCGD000002 二极管 2 D9110 B0JCGD000002 二极管 1 D9400,01 MA152K 二极管 2 D9800 B0JCME000037 二极管 1 D9801 B0JCDD000002 二极管 1 D9802 MA728 二极管 1 D9804 MA152K 二极管 1 D9807,08 MA152K 二极管 2 D9812 B0JCME000037 二极管 1 D9813 B0JCDD000002 二极管 1 D9814 B0JCME000037 二极管 1 D9815 B0JCDD000002 二极管 1 DG1 K1KY80A00011 80P 连接接头 1 DG2 K1KA15B00074 15P 连接接头 1 DG3 K1KY40B00003 40P 连接接头 1 DG5 K1KB21BA0063 21P 连接接头 1 DG8,G9 K1FY119D0001 连接接头 2 DG15 K1KY40B00003 40P 连接接头 1 DG20 K1MN40B00045 40P 连接接头 1 DG35 K1KA07BA0047 7P 连接接头 1 FL3301,02 J0HABB000003 LC 滤波器 2 FL3303-05 J0HABB000004 LC 滤波器 3 FL7101 J0HABH000013 LC 滤波器 1 FL7201 J0HABH000013 LC 滤波器 1 FL9302-04 F1J1E1040022 C 0.10UF, Z, 25V 3 FL9305,06 J0HABH000013 LC 滤波器 2 FL9400,01 J0HABH000013 LC 滤波器 2 FL9402-04 F1J1E1040022 C 0.10UF, Z, 25V 3 FL9501,02 J0HABH000013 LC 滤波器 2 FL9800,01 J0HABH000013 LC 滤波器 2 FL9803,04 J0HABH000012 LC 滤波器 2 FL9805-07 J0HABH000013 LC 滤波器 3 G1 K1KA12A00317 12P 连接接头 1 G3 K1KA03BA0047 3P 连接接头 1 G51 K1KA30AA0009 30P 连接接头 1 GK3 K1KA03BA0061 3P 连接接头 1 H1 K1KY80A00011 80P 连接接头 1 H2 K1KA15A00148 15P 连接接头 1 H5,H6 K1KA15AA0288 15P 连接接头 2 H15 K1KA04AA0150 4P 连接接头 1 H40 K1KA20AA0009 20P 连接接头 1 H51 K1KA30AA0009 30P 连接接头 1 参考号 部品号 部品名称 & 说明 件数 备注 135 HC01 K1KA21A00011 21P 连接接头 1 HC12 K1KA09AA0190 9P 连接接头 1 HC15 K1KY40B00003 40P 连接接头 1 HC21 K1KA08AA0193 8P 连接接头 1 HC22 K1KA11AA0194 11P 连接接头 1 IC1100 C3ABPG000145 IC 1 IC1101 TVRP178 IC 1 IC1102 TVRP177 IC 1 IC1103 MN103SB20RGL IC 1 IC1110 C0CBCAD00016 IC 1 IC1111 C0EBY0000041 IC 1 IC2103 AN77L08M IC 1 IC2104 C0ABBA000168 IC 1 IC2105 AN15862A-VT IC 1 IC2106 C1AB00002468 IC 1 IC2109 C1BB00000947 IC 1 IC2110 AN7705SP IC 1 IC2302 C1AB00002451 IC 1 IC2304 C0ABBA000168 IC 1 IC2306 C0ABBA000168 IC 1 IC2511 B3L000000020 IC 1 IC3005 AN15867A-VT IC 1 IC3301 C0JBAZ002205 IC 1 IC4013 C0CBCBF00009 IC 1 IC4016 C0CBCAC00275 IC 1 IC4018 C0CBCAC00275 IC 1 IC4019 C1AB00002665 IC 1 IC4022 TVRN916 IC 1 IC4023 TVRN917 IC 1 IC4025 C0FBBK000038 IC 1 IC4026 C1AB00002535 IC 1 IC4027 C0DBFFD00003 IC 1 IC4028 C0ABBB000230 IC 1 IC4029 C0CBCAC00282 IC 1 IC4030 C0CBCBC00190 IC 1 IC4032 C0DBGYY00052 IC 1 IC4035 C0CBCAF00031 IC 1 IC4036 C0JBAP000020 IC 1 IC4037 MN84522-A IC 1 IC4038 C3ABQJ000048 IC 1 IC5601 N0BG2DE00001 IC 1 IC5602 EHMDD9851 线性 IC 1 IC5603 C0DBAJB00004 IC 1 IC5604 C0DBZGC00067 IC 1 IC5801 C0DBAZF00003 IC 1 IC6131 C0ZBZ0000895 IC 1 IC6151 C0ZBZ0001324 IC 1 IC6191 C0ZBZ0000895 IC 1 IC6211 C0ZBZ0001325 IC 1 IC6221 C0DBEMB00005 IC 1 IC6241 C0JBAZ000005 IC 1 IC6251 NJM2903M 集成电路 1 IC6471 C0DBEKA00003 IC 1 IC6472 C0JBAA000377 IC 1 IC6501 C0ZBZ0000895 IC 1 IC6521 C0ZBZ0001324 IC 1 IC6561,62 C0JBAZ000005 IC 2 IC6581 NJM2903M 集成电路 1 IC6601 C0ZBZ0001325 IC 1 IC6602 C0JBAB000715 IC 1 IC6610 NJM2903M 集成电路 1 IC6671 C0ZBZ0001325 IC 1 IC6681 C0ZBZ0001325 IC 1 IC6682 C0JBAA000377 IC 1 IC6721,22 C0JBAZ000994 IC 2 IC6724,25 C0CBADC00089 IC 2 IC6751 C0CBADC00089 IC 1 IC6752 C0ZBZ0001325 IC 1 IC6753 C0JBAB000715 IC 1 IC6771 C0CBADC00089 IC 1 IC6772 C0ZBZ0001325 IC 1 IC6773,74 C0JBAA000377 IC 2 IC6791 N0BF1FB00001 IC 1 IC6801,02 C0DBEMB00005 IC 2 IC6821 C0DBEMB00005 IC 1 IC6841 C0DBEMB00005 IC 1 参考号 部品号 部品名称 & 说明 件数 备注 IC6861 NJM2903M 集成电路 1 IC6871 NJM2903M 集成电路 1 IC6901-06 AN16072A-VT IC 6 IC6951-56 AN16072A-VT IC 6 IC7101-08 C0JBAZ001120 IC 8 IC7201-06 C0JBAZ001120 IC 6 IC9001 TVRP174 IC 1 IC9002 C0ZBZ0001330 IC 1 IC9003 TVRP173-1 IC 1 IC9007 TVRP175-1 IC 1 IC9011 C0EBF0000431 IC 1 IC9200 C1ZBZ0003186 IC 1 IC9300 MN84521-A IC 1 IC9301 C3ABQJ000051 IC 1 IC9304 TVRP176 IC 1 IC9400 MN84521-A IC 1 IC9401 C3ABQJ000051 IC 1 IC9402 C0JBAZ002614 IC 1 IC9500 C1ZBZ0002599 IC 1 IC9503 C0JBAZ001120 IC 1 IC9505 C0JBAZ001120 IC 1 IC9602 PST9128NR IC ( 逻辑 ) 1 IC9800 C0DBAYY00054 IC 1 IC9801 C0DBZFG00066 IC 1 IC9802,03 C0JBAZ001120 IC 2 IC9806 C0DBAHD00011 IC 1 IC9807 C0DBAYY00054 IC 1 IC9809 C0DBAYY00054 IC 1 JK2003 K2HA204A0038 插孔 1 JK3001 K1FB315A0005 插孔 1 JK3100 TJB0A639 端子 1 JK3701C K4AK22B00002 端子板 1 JS012 ERJ3GEY0R00 M 0 OHM, 1/16W 1 JS1100-02 ERJ2GE0R00 M 0.0 OHM, J,0.063W 3 JS1109 ERJ2GE0R00 M 0.0 OHM, J,0.063W 1 JS1117 ERJ2GE0R00 M 0.0 OHM, J,0.063W 1 JS2021,22 ERJ3GEY0R00 M 0 OHM, 1/16W 2 JS2026 ERJ3GEY0R00 M 0 OHM, 1/16W 1 JS2031-33 ERJ3GEY0R00 M 0 OHM, 1/16W 3 JS2108,09 ERJ3GEY0R00 M 0 OHM, 1/16W 2 JS2123,24 ERJ3GEY0R00 M 0 OHM, 1/16W 2 JS2300-03 ERJ6GEY0R00 M 0 OHM, 1/10W 4 JS2319 ERJ6GEY0R00 M 0 OHM, 1/10W 1 JS2331 ERJ6GEY0R00 M 0 OHM, 1/10W 1 JS3002 ERJ3GEY0R00 M 0 OHM, 1/16W 1 JS3010-15 ERJ6GEY0R00 M 0 OHM, 1/10W 6 JS3023 ERJ3GEY0R00 M 0 OHM, 1/16W 1 JS3029 ERJ3GEY0R00 M 0 OHM, 1/16W 1 JS3033-35 ERJ3GEY0R00 M 0 OHM, 1/16W 3 JS3202 J0JCC0000241 片状电感 1 JS3205 J0JCC0000241 片状电感 1 JS3206 ERJ3GEY0R00 M 0 OHM, 1/16W 1 JS3215 ERJ6GEY0R00 M 0 OHM, 1/10W 1 JS3230 ERJ3GEY0R00 M 0 OHM, 1/16W 1 JS3237 ERJ3GEY0R00 M 0 OHM, 1/16W 1 JS3239 ERJ3GEY0R00 M 0 OHM, 1/16W 1 JS3244,45 J0JCC0000241 片状电感 2 JS3246 ERJ6GEY0R00 M 0 OHM, 1/10W 1 JS3252 ERJ6GEY0R00 M 0 OHM, 1/10W 1 JS3255 ERJ6GEY0R00 M 0 OHM, 1/10W 1 JS3256 ERJ3GEY0R00 M 0 OHM, 1/16W 1 JS3265,66 ERJ3GEY0R00 M 0 OHM, 1/16W 2 JS3302-04 ERJ3GEY0R00 M 0 OHM, 1/16W 3 JS3307-12 ERJ3GEY0R00 M 0 OHM, 1/16W 6 JS3352 J0JCC0000241 片状电感 1 JS3354-59 J0JCC0000241 片状电感 6 JS3362,63 ERJ3GEY0R00 M 0 OHM, 1/16W 2 JS3368 ERJ3GEY0R00 M 0 OHM, 1/16W 1 JS3402,03 ERJ3GEY0R00 M 0 OHM, 1/16W 2 JS3404,05 ERJ6GEY0R00 M 0 OHM, 1/10W 2 JS3704,05 ERJ6GEY0R00 M 0 OHM, 1/10W 2 JS3707,08 ERJ6GEY0R00 M 0 OHM, 1/10W 2 JS3711-14 ERJ6GEY0R00 M 0 OHM, 1/10W 4 JS3716 ERJ3GEY0R00 M 0 OHM, 1/16W 1 JS4016,17 ERJ2GE0R00 M 0.0 OHM, J,0.063W 2 参考号 部品号 部品名称 & 说明 件数 备注 136 JS4022-24 ERJ2GE0R00 M 0.0 OHM, J,0.063W 3 JS4025,26 ERJ2GEJ101 M 100 OHM, J,0.063W 2 JS4027,28 ERJ2GE0R00 M 0.0 OHM, J,0.063W 2 JS4029 ERJ2GEJ221 M 220 OHM, J,0.063W 1 JS4033-40 ERJ2GE0R00 M 0.0 OHM, J,0.063W 8 JS4046 ERJ2GE0R00 M 0.0 OHM, J,0.063W 1 JS4069 ERJ2GEJ221 M 220 OHM, J,0.063W 1 JS4103,04 ERJ2GE0R00 M 0.0 OHM, J,0.063W 2 JS4111 ERJ3GEY0R00 M 0 OHM, 1/16W 1 JS4117,18 ERJ2GE0R00 M 0.0 OHM, J,0.063W 2 JS5602 ERJ3GEY0R00 M 0 OHM, 1/16W 1 K1 K1KY12B00001 12P 连连接头 1 L001 J0JGC0000021 片状电感线圈 1 L007 J0JCC0000241 片状电感 1 L010,11 J0JCC0000241 片状电感 2 L013 J0JCC0000241 片状电感 1 L021 ERJ3GEY0R00 M 0 OHM, 1/16W 1 L031,32 J0JGC0000021 片状电感线圈 2 L1101-04 J0JHC0000078 片状电感 4 L1109 J0JHC0000078 片状电感 1 L2001,02 J0JCC0000364 片状电感 2 L2003,04 TSK1032 头扼流圈 2 L2007,08 TSK1032 头扼流圈 2 L2011,12 TSK1032 头扼流圈 2 L2015,16 TSK1032 头扼流圈 2 L2107 TSK1032 头扼流圈 1 L2108 J0JCC0000241 片状电感 1 L2109,10 TSK1032 头扼流圈 2 L2111,12 J0JCC0000241 片状电感 2 L2115 J0JCC0000241 片状电感 1 L2117 ELESE6R8KA 校正线圈 1 L2118 EXCELDR35C 头扼流圈 1 L2123 J0JCC0000241 片状电感 1 L2178,79 J0JCC0000241 片状电感 2 L2182-87 J0JCC0000241 片状电感 6 L2204 ERJ3GEY0R00 M 0 OHM, 1/16W 1 L2205,06 J0JCC0000241 片状电感 2 L2300-03 G0C330MA0049 校正线圈 4 L2308 TALL08N3R9MA 感应线圈 1 L3000 G0C101K00023 校正线圈 1 L3001-03 TSK1032 头扼流圈 3 L3009,10 TSK1032 头扼流圈 2 L3013 TSK1032 头扼流圈 1 L3026 TSK1032 头扼流圈 1 L3212 TSK1032 头扼流圈 1 L3216 J0JGC0000021 片状电感线圈 1 L3219 J0JGC0000021 片状电感线圈 1 L3700,01 J0JCC0000364 片状电感 2 L3707,08 TSK1032 头扼流圈 2 L4023 J0JHC0000078 片状电感 1 L4029 J0JHC0000078 片状电感 1 L4031 J0JHC0000078 片状电感 1 L4038 J0JHC0000078 片状电感 1 L4040-46 J0JHC0000078 片状电感 7 L4048 J0JHC0000078 片状电感 1 L4049 J0JBC0000080 片状电感 1 L4050,51 J0JHC0000078 片状电感 2 L4052 J0JCC0000077 片状电感 1 L4053-55 J0JHC0000078 片状电感 3 L4056,57 J0JCC0000077 片状电感 2 L4060,61 J0JCC0000077 片状电感 2 L4065,66 J0JHC0000078 片状电感 2 L4068-70 J0JHC0000078 片状电感 3 L4071 J0JBC0000080 片状电感 1 L4073 J0JHC0000078 片状电感 1 L4075,76 J0JHC0000078 片状电感 2 L4077 J0JCC0000077 片状电感 1 L4078 J0JHC0000078 片状电感 1 L5602 TALL08N2R7MA 感应线圈 1 L5604 TALL08N2R7MA 感应线圈 1 L5605 G0A2R7ZA0021 扼流线圈 1 L5606,07 G0A220GA0002 扼流线圈 2 L5608 G1C100MA0072 感应线圈 1 L5609 G0A220GA0002 扼流线圈 1 L5610 G1C470MA0077 感应线圈 1 参考号 部品号 部品名称 & 说明 件数 备注 L5612 TALL08N2R7MA 感应线圈 1 L5615 TALL08N150KA 感应线圈 1 L5621,22 G1C330MA0234 感应线圈 2 L5623 G1C150MA0234 感应线圈 1 L5624 G1C330MA0234 感应线圈 1 L5651 G0A220GA0002 扼流线圈 1 L5801 G0C101K00023 校正线圈 1 L5802 TALL08N101KA 感应线圈 1 L6001-03 G0C1R9KA0147 校正线圈 3 L6011-13 G0C1R9KA0147 校正线圈 3 L6061-68 G0ZZ00002183 校正线圈 8 L6081-88 G0ZZ00002183 校正线圈 8 L6101,02 J0JJC0000011 片状电感 2 L6103 G0ZZ00002183 校正线圈 1 L6104,05 J0JJC0000011 片状电感 2 L6211,12 J0JJC0000011 片状电感 2 L6221 G0ZZ00002183 校正线圈 1 L6241 G0ZZ00002183 校正线圈 1 L6262 G0ZZ00002183 校正线圈 1 L6271,72 G0ZZ00002183 校正线圈 2 L6401-03 G0C1R9KA0147 校正线圈 3 L6411-13 G0C1R9KA0147 校正线圈 3 L6461-68 G0ZZ00002183 校正线圈 8 L6472,73 G0ZZ00002183 校正线圈 2 L6481-88 G0ZZ00002183 校正线圈 8 L6591,92 G0ZZ00002183 校正线圈 2 L6601,02 G0ZZ00002183 校正线圈 2 L6801,02 J0JJC0000011 片状电感 2 L6841 J0JJC0000011 片状电感 1 L9501,02 J0JHC0000078 片状电感 2 L9503 G1C150KA0038 感应线圈 1 L9800 G1C3R0MA0248 感应线圈 1 L9801,02 G1C2R2MA0241 感应线圈 2 L9810 J0JHC0000045 片状电感 1 PA2 K1KA05AA0192 5P 连连接头 1 PA5 K1KA11AA0194 11P 连连接头 1 PA10 K1KA06A00452 6P 连连接头 1 PA20 K1MN40A00024 40P 连连接头 1 PA31-34 K1KA03AA0192 3P 连连接头 4 PA40 K1KA20AA0009 20P 连连接头 1 PA1101 K5H8012A0023 保险丝 1 PA2055 K5H1622A0023 保险丝 1 PA3100 K5H1622A0023 保险丝 1 PA3104 ERJ3GEY0R00 M 0 OHM, 1/16W 1 PA9800 K5H4022A0023 保险丝 1 PC6480 B3PBA0000223 IC 1 PC6701-03 B3PBA0000233 IC 3 PC6704 B3PBA0000234 IC 1 PC6705 B3PBA0000233 IC 1 PC6760 B3PBA0000223 IC 1 PC6801 B3PBA0000223 IC 1 PC6861 B3PBA0000223 IC 1 PC6871 B3PBA0000223 IC 1 Q002 2SA207700L 三极管 1 Q1100-03 2SC584500L 三极管 4 Q1108 2SC584500L 三极管 1 Q1109,10 B1CBHD000002 FET 2 Q1111 2SC584500L 三极管 1 Q1113-16 2SC584500L 三极管 4 Q1130,31 2SC584500L 三极管 2 Q1134,35 2SC584500L 三极管 2 Q1137 2SC584500L 三极管 1 Q1139-43 2SC584500L 三极管 5 Q2001,02 2SC584500L 三极管 2 Q2011 2SA207700L 三极管 1 Q2012 B1ABDF000034 三极管 1 Q2013 2SA207700L 三极管 1 Q2102-05 2SA207700L 三极管 4 Q2106 B1ABDF000034 三极管 1 Q2108 B1ABDF000034 三极管 1 Q2113,14 B1ABDF000034 三极管 2 Q2300 2SA207700L 三极管 1 PA Q2300 B1ABDF000034 三极管 1 H Q2301 2SD601A 三极管 1 参考号 部品号 部品名称 & 说明 件数 备注 137 Q2302 2SD601A 三极管 1 PA Q2302 B1ABDF000034 三极管 1 H Q2303 2SD601A 三极管 1 Q2306,07 2SA207700L 三极管 2 Q2314-17 B1ABDF000034 三极管 4 Q2510,11 2SD601A 三极管 2 Q2513 2SD601A 三极管 1 Q3002 2SA207700L 三极管 1 Q3008 2SA207700L 三极管 1 Q3011 2SA207700L 三极管 1 Q3014,15 2SA207700L 三极管 2 Q3017 2SA207700L 三极管 1 Q3204-07 B1ABDF000034 三极管 4 Q3210 2SA207700L 三极管 1 Q3331-33 2SC2480 三极管 3 Q4050 2SC584500L 三极管 1 Q4053 2SC584500L 三极管 1 Q4055-59 2SA207700L 三极管 5 Q4061-69 2SC584500L 三极管 9 Q4070,71 B1MBACA00008 三极管 2 Q4082,83 2SK1228 FET 2 Q4084 2SC584500L 三极管 1 Q4918,19 2SC584500L 三极管 2 Q5601 B1DHDC000028 三极管 1 Q5602 2SD601A 三极管 1 Q5603 B1DHDC000028 三极管 1 Q5604,05 2SD601A 三极管 2 Q5610 2SD601A 三极管 1 Q5613 2SD601A 三极管 1 Q5614 2SK3065T100 FET 1 Q5641-43 2SA207700L 三极管 3 Q5644 2SD601A 三极管 1 Q6001-03 B1JADN000001 三极管 3 Q6021-23 B1JADN000001 三极管 3 Q6041,42 B1JADN000002 三极管 2 Q6051,52 B1JADN000002 三极管 2 Q6101-04 B1DFKM000002 三极管 4 Q6105 B1ABNF000006 三极管 1 Q6106 B1ADNF000006 三极管 1 Q6111 2SK326800L FET 1 Q6112 B1DFKM000002 三极管 1 Q6114 B1DFKM000002 三极管 1 Q6141 B1ABNF000006 三极管 1 Q6142 B1ADNF000006 三极管 1 Q6146 B1ABNF000006 三极管 1 Q6147 B1ADNF000006 三极管 1 Q6171 B1ABRD000003 三极管 1 Q6172 B1ADRD000001 三极管 1 Q6181 B1ABRD000003 三极管 1 Q6182 B1ADRD000001 三极管 1 Q6221 2SD1263A 三极管 1 Q6222 2SC3063 三极管 1 Q6251 2SD601A 三极管 1 Q6401-03 B1JADN000001 三极管 3 Q6421-23 B1JAEP000001 三极管 3 Q6441,42 B1JADN000002 三极管 2 Q6451,52 B1JADP000002 三极管 2 Q6471 B1CHGD000006 三极管 1 Q6511 B1ABNF000006 三极管 1 Q6512 B1ADNF000006 三极管 1 Q6516 B1ABNF000006 三极管 1 Q6517 B1ADNF000006 三极管 1 Q6531 B1ABRD000003 三极管 1 Q6532 B1ADRD000001 三极管 1 Q6551 B1ABRD000003 三极管 1 Q6552 B1ADRD000001 三极管 1 Q6581 2SD601A 三极管 1 Q6601 B1DFES000003 三极管 1 Q6602 2SD601A 三极管 1 Q6621,22 B1DFKM000001 三极管 2 Q6641,42 B1DFKM000001 三极管 2 Q6644,45 B1DFKM000001 三极管 2 Q6647,48 B1DFKM000001 三极管 2 Q6661 B1DEET000002 三极管 1 Q6662 2SD601A 三极管 1 Q6663 2SD2185 三极管 1 Q6671,72 B1DFET000001 三极管 2 参考号 部品号 部品名称 & 说明 件数 备注 Q6680 B1ADNF000006 三极管 1 Q6681,82 2SK389500L FET 2 Q6691 2SK620 FET 1 Q6742,43 2SD601A 三极管 2 Q6744 2SK620 FET 1 Q6762 B1ADNF000006 三极管 1 Q6781 B1ABNF000006 三极管 1 Q6782 B1ADNF000006 三极管 1 Q6791 2SD601A 三极管 1 Q6801 B1BAEJ000014 三极管 1 Q6802 2SB0709A 三极管 1 Q6803 2SD814A 三极管 1 Q6804 2SD601A 三极管 1 Q6821 2SD1263A 三极管 1 Q6822 2SC3063 三极管 1 Q6824 2SD601A 三极管 1 Q6841 2SD1263A 三极管 1 Q6842 2SC1473A 三极管 1 Q9044 2SD601A 三极管 1 Q9046 2SD601A 三极管 1 Q9050-54 2SD601A 三极管 5 Q9057,58 B1CBHD000002 FET 2 Q9100 2SD601A 三极管 1 Q9200,01 B1CBHD000002 FET 2 Q9400-02 2SD601A 三极管 3 Q9800,01 B1MBEDA00015 三极管 2 Q9803 B1MBEDA00015 三极管 1 Q9805,06 2SD601A 三极管 2 R001 ERJ3GEYJ102 M 1KOHM,J,1/16W 1 R005 ERJ3GEYJ561 M 560 OHM,J,1/16W 1 R008 ERJ3GEY0R00 M 0 OHM, 1/16W 1 R009 ERJ3GEYJ221 M 220 OHM,J,1/16W 1 R011 ERJ6GEYJ271 M 270 OHM,J,1/10W 1 R014 ERJ3GEY0R00 M 0 OHM, 1/16W 1 R017,18 ERJ3GEYJ220 M 22 OHM,J,1/16W 2 R019,20 ERJ3GEY0R00 M 0 OHM, 1/16W 2 R021 ERJ3GEYJ102 M 1KOHM,J,1/16W 1 R022 ERJ3GEYJ221 M 220 OHM,J,1/16W 1 R023 ERJ3GEY0R00 M 0 OHM, 1/16W 1 R028 ERJ3EKF1503 M 150KOHM, 1/16W 1 R029 ERJ3EKF2703 M 270KOHM, 1/16W 1 R1101 ERJ2GEJ101 M 100 OHM, J,0.063W 1 R1102,03 ERJ2GEJ102 M 1KOHM, J,0.063W 2 R1105,06 ERJ2GEJ102 M 1KOHM, J,0.063W 2 R1113 ERJ2GEJ332 M 3.3KOHM, J,0.063W 1 R1116 ERJ2GEJ562 M 5.6KOHM,J,0.063W 1 R1117 ERJ2GE0R00 M 0.0 OHM, J,0.063W 1 R1118,19 EXB2HV680J 电阻阵列 2 R1121,22 ERJ2GEJ220 M 22 OHM, J,0.063W 2 R1123 ERJ2GEJ473 M 47KOHM,J,0.063W 1 R1124,25 ERJ2GEJ332 M 3.3KOHM, J,0.063W 2 R1129,30 ERJ2GEJ473 M 47KOHM,J,0.063W 2 R1131,32 ERJ2GEJ101 M 100 OHM, J,0.063W 2 R1133,34 ERJ2GEJ102 M 1KOHM, J,0.063W 2 R1135 ERJ2GEJ103 M 10KOHM, J,0.063W 1 R1140,41 ERJ2GEJ680 M 68 OHM, J,0.063W 2 R1146 ERJ2GEJ271 M 270 OHM, J,0.063W 1 R1147,48 D1HG5608A002 排阻 2 R1149 EXB2HV680J 电阻阵列 1 R1151 ERJ2GEJ101 M 100 OHM, J,0.063W 1 R1152 ERJ2GEJ102 M 1KOHM, J,0.063W 1 R1153 ERJ2GEJ101 M 100 OHM, J,0.063W 1 R1154,55 ERJ2GEJ472 M 4.7KOHM, J,0.063W 2 R1156 ERJ2GEJ104 M 100KOHM, J,0.063W 1 R1157 ERJ2GEJ101 M 100 OHM, J,0.063W 1 R1158 ERJ2GEJ273 M 27KOHM ,J,0.063W 1 R1159 ERJ2GEJ123X M 12KOHM ,J,0.063W 1 R1160 ERJ2GEJ473 M 47KOHM,J,0.063W 1 R1162 ERJ2GEJ473 M 47KOHM,J,0.063W 1 R1164 ERJ2GEJ123X M 12KOHM ,J,0.063W 1 R1165 ERJ2GEJ153 M 15KOHM ,J,0.063W 1 R1168,69 ERJ2GE0R00 M 0.0 OHM, J,0.063W 2 R1174 ERJ2GEJ101 M 100 OHM, J,0.063W 1 R1175 ERJ2GEJ563 M 56KOHM ,J,0.063W 1 R1176 ERJ2GEJ123X M 12KOHM ,J,0.063W 1 R1177-79 ERJ2GEJ101 M 100 OHM, J,0.063W 3 参考号 部品号 部品名称 & 说明 件数 备注 138 R1181 ERJ2GEJ101 M 100 OHM, J,0.063W 1 R1182 ERJ2GEJ683 M 68KOHM, J,0.063W 1 R1183 EXB28V680JX 电阻阵列 1 R1184 ERJ2GE0R00 M 0.0 OHM, J,0.063W 1 R1186 ERJ2GEJ473 M 47KOHM,J,0.063W 1 R1187 EXB2HV680J 电阻阵列 1 R1188,89 ERJ2GEJ103 M 10KOHM, J,0.063W 2 R1191 ERJ2GEJ473 M 47KOHM,J,0.063W 1 R1197 ERJ2GEJ473 M 47KOHM,J,0.063W 1 R1199 ERJ2GEJ473 M 47KOHM,J,0.063W 1 R1200 EXB2HV680J 电阻阵列 1 R1203 ERJ2GEJ102 M 1KOHM, J,0.063W 1 R1207 ERJ2GEJ104 M 100KOHM, J,0.063W 1 R1212 ERJ2GE0R00 M 0.0 OHM, J,0.063W 1 R1214 ERJ2GEJ103 M 10KOHM, J,0.063W 1 R1215-17 ERJ2GEJ101 M 100 OHM, J,0.063W 3 R1218 ERJ2GEJ680 M 68 OHM, J,0.063W 1 R1220 ERJ2GEJ680 M 68 OHM, J,0.063W 1 R1221 ERJ2GEJ332 M 3.3KOHM, J,0.063W 1 R1222 ERJ2GEJ330 M 33 OHM, J,0.063W 1 R1223 ERJ2GEJ102 M 1KOHM, J,0.063W 1 R1224 ERJ2GEJ473 M 47KOHM,J,0.063W 1 R1225,26 ERJ2GEJ220 M 22 OHM, J,0.063W 2 R1228 ERJ2GEJ220 M 22 OHM, J,0.063W 1 R1229 ERJ2GEJ182 M 1.8KOHM, J,0.063W 1 R1230 ERJ2GEJ220 M 22 OHM, J,0.063W 1 R1231 ERJ2GEJ473 M 47KOHM,J,0.063W 1 R1232,33 ERJ2GEJ332 M 3.3KOHM, J,0.063W 2 R1234 ERJ2GE0R00 M 0.0 OHM, J,0.063W 1 R1235,36 ERJ2GEJ272 M 2.7KOHM, J,0.063W 2 R1238 ERJ2GEJ473 M 47KOHM,J,0.063W 1 R1239 ERJ3EKF1202 M 12KOHM, 1/16W 1 R1240 ERJ2GEJ473 M 47KOHM,J,0.063W 1 R1241 ERJ2GEJ822 M 8.2KOHM, J,0.063W 1 R1243 ERJ2GEJ102 M 1KOHM, J,0.063W 1 R1246 ERJ2GEJ912 M 9.1KOHM, J,0.063W 1 R1249 ERJ2GEJ473 M 47KOHM,J,0.063W 1 R1250 ERJ2GEJ224 M 220KOHM, J,0.063W 1 R1251,52 EXB2HV101J 电阻阵列 2 R1256 ERJ2GEJ102 M 1KOHM, J,0.063W 1 R1263,64 ERJ2GEJ101 M 100 OHM, J,0.063W 2 R1269 ERJ2GE0R00 M 0.0 OHM, J,0.063W 1 R1270,71 ERJ2GEJ220 M 22 OHM, J,0.063W 2 R1275 ERJ3EKF7151 M7.15KOHM, 1/16W 1 R1279,80 ERJ2GEJ220 M 22 OHM, J,0.063W 2 R1281 ERJ2GEJ102 M 1KOHM, J,0.063W 1 R1282 ERJ2GEJ153 M 15KOHM ,J,0.063W 1 R1283 ERJ2GEJ101 M 100 OHM, J,0.063W 1 R1284 ERJ2GEJ682 M 6.8KOHM, J,0.063W 1 R1290 ERJ2GEJ472 M 4.7KOHM, J,0.063W 1 R1299-02 ERJ2GE0R00 M 0.0 OHM, J,0.063W 4 R1307 ERJ2GEJ104 M 100KOHM, J,0.063W 1 R1308 ERJ2GEJ273 M 27KOHM ,J,0.063W 1 R1309-12 ERJ2GEJ220 M 22 OHM, J,0.063W 4 R1313,14 ERJ2GEJ103 M 10KOHM, J,0.063W 2 R1315 ERJ2GEJ333 M 33KOHM, J,0.063W 1 R1316 ERJ2GEJ103 M 10KOHM, J,0.063W 1 R1318,19 ERJ2GEJ512X M5.12KOHM, J,0.063W 2 R1321 ERJ2GEJ153 M 15KOHM ,J,0.063W 1 R1322 ERJ2GEJ100 M 10 OHM, J,0.063W 1 R1323,24 ERJ2GEJ823 M 82KOHM, J,0.063W 2 R1325,26 ERJ2GEJ104 M 100KOHM, J,0.063W 2 R1327,28 ERJ2GEJ683 M 68KOHM, J,0.063W 2 R1329,30 ERJ2GEJ473 M 47KOHM,J,0.063W 2 R1331,32 ERJ2GEJ104 M 100KOHM, J,0.063W 2 R1333 ERJ2GEJ101 M 100 OHM, J,0.063W 1 R1340 ERJ2GEJ473 M 47KOHM,J,0.063W 1 R1344 ERJ2GEJ101 M 100 OHM, J,0.063W 1 R1346 ERJ2GEJ473 M 47KOHM,J,0.063W 1 R1351 ERJ2GEJ101 M 100 OHM, J,0.063W 1 R1352 ERJ2GEJ473 M 47KOHM,J,0.063W 1 R1354 ERJ2GEJ101 M 100 OHM, J,0.063W 1 R1363 ERJ2GEJ473 M 47KOHM,J,0.063W 1 R1367 ERJ2GEJ333 M 33KOHM, J,0.063W 1 R1368 ERJ2GEJ183 M 18KOHM ,J,0.063W 1 R1369 ERJ2GE0R00 M 0.0 OHM, J,0.063W 1 R1372 ERJ2GEJ473 M 47KOHM,J,0.063W 1 参考号 部品号 部品名称 & 说明 件数 备注 R1375 ERJ2GEJ104 M 100KOHM, J,0.063W 1 R1376 ERJ2GEJ273 M 27KOHM ,J,0.063W 1 R1377 ERJ8GEY0R00 M 0 OHM, 1/8W 1 R1379 ERJ2GEJ331 M 330 OHM, J,0.063W 1 R1382,83 ERJ2GE0R00 M 0.0 OHM, J,0.063W 2 R1384 ERJ2GEJ101 M 100 OHM, J,0.063W 1 R1389 ERJ2GE0R00 M 0.0 OHM, J,0.063W 1 R1408 ERJ2GEJ104 M 100KOHM, J,0.063W 1 R1410 ERJ2GEJ102 M 1KOHM, J,0.063W 1 R1411 ERJ2GEJ472 M 4.7KOHM, J,0.063W 1 R1412,13 ERJ2GEJ104 M 100KOHM, J,0.063W 2 R1414 ERJ2GE0R00 M 0.0 OHM, J,0.063W 1 R1426-32 ERJ8GEY0R00 M 0 OHM, 1/8W 7 R1436,37 ERJ2GEJ561 M 60 OHM, J,0.063W 2 R1439 ERJ2GEJ271 M 270 OHM, J,0.063W 1 R1441 ERJ2GE0R00 M 0.0 OHM, J,0.063W 1 R1446,47 ERJ2GEJ471 M 470 OHM, J,0.063W 2 R1448,49 ERJ2GEJ473 M 47KOHM,J,0.063W 2 R1451,52 ERJ2GEJ473 M 47KOHM,J,0.063W 2 R1454 ERJ2GE0R00 M 0.0 OHM, J,0.063W 1 R1458,59 ERJ2GEJ101 M 100 OHM, J,0.063W 2 R1461,62 ERJ2GE0R00 M 0.0 OHM, J,0.063W 2 R1466 ERJ2GEJ103 M 10KOHM, J,0.063W 1 R1467 ERJ2GEJ473 M 47KOHM,J,0.063W 1 R1470 ERJ2GE0R00 M 0.0 OHM, J,0.063W 1 R1472,73 ERJ2GEJ301 M 300 OHM, J,0.063W 2 R1474 ERJ8GEY0R00 M 0 OHM, 1/8W 1 R1475 ERJ2GEJ271 M 270 OHM, J,0.063W 1 R1478 ERJ2GEJ680 M 68 OHM, J,0.063W 1 R1479,80 ERJ2GEJ473 M 47KOHM,J,0.063W 2 R1490 ERJ2GE0R00 M 0.0 OHM, J,0.063W 1 R1526 ERJ2GEJ102 M 1KOHM, J,0.063W 1 R1530,31 ERJ2GE0R00 M 0.0 OHM, J,0.063W 2 R1554,55 ERJ3GEY0R00 M 0 OHM, 1/16W 2 R1556 ERJ2GEJ331 M 330 OHM, J,0.063W 1 R2005 ERJ3GEYJ104 M 100KOHM,J,1/16W 1 R2006-11 ERJ6GEYJ223 M 22KOHM,J,1/10W 6 R2012 ERJ3GEYJ104 M 100KOHM,J,1/16W 1 R2013,14 ERJ3GEYJ222 M 2.2KOHM,J,1/16W 2 R2015,16 ERJ3GEYJ331 M 330 OHM,J,1/16W 2 R2042 ERJ3GEYJ105 M 1MOHM,J,1/16W 1 R2043 ERJ3GEYJ473 M 47KOHM,J,1/16W 1 R2044 ERJ3GEYJ102 M 1KOHM,J,1/16W 1 R2045,46 ERJ3GEYJ103 M 10KOHM,J,1/16W 2 R2048 ERJ6GEYJ471 M 470 OHM,J,1/10W 1 R2049,50 ERJ3GEYJ103 M 10KOHM,J,1/16W 2 R2051,52 ERJ6GEYJ184 M 180KOHM,J,1/10W 2 R2053 ERJ6GEYJ471 M 470 OHM,J,1/10W 1 R2054 ERJ3GEYJ103 M 10KOHM,J,1/16W 1 R2113,14 ERJ3GEY0R00 M 0 OHM, 1/16W 2 R2116 J0JCC0000241 片状电感 1 R2124,25 ERJ3GEYJ101 M 100 OHM,J,1/16W 2 R2126,27 ERJ3GEYJ472 M 4.7KOHM,J,1/16W 2 R2128,29 ERJ3GEYJ101 M 100 OHM,J,1/16W 2 R2130 ERJ3EKF1002 M 10KOHM, 1/16W 1 R2131 ERJ3EKF8201 M 8.2KOHM, 1/16W 1 R2132 ERJ3GEYJ333 M 33KOHM,J,1/16W 1 R2133 ERJ3GEY0R00 M 0 OHM, 1/16W 1 R2137 ERJ3GEYJ333 M 33KOHM,J,1/16W 1 R2138 ERJ3EKF1002 M 10KOHM, 1/16W 1 R2147 ERJ3EKF1002 M 10KOHM, 1/16W 1 R2148,49 ERJ3EKF6342 M6.34KOHM, 1/16W 2 R2152 ERJ3GEYJ220 M 22 OHM,J,1/16W 1 R2153 ERJ3GEYJ221 M 220 OHM,J,1/16W 1 R2154 ERJ3GEYJ220 M 22 OHM,J,1/16W 1 R2155,56 ERJ3GEYJ221 M 220 OHM,J,1/16W 2 R2158 ERJ3GEYJ221 M 220 OHM,J,1/16W 1 R2160 ERJ3GEYJ221 M 220 OHM,J,1/16W 1 R2162 ERJ3GEYJ221 M 220 OHM,J,1/16W 1 R2164 ERJ3GEYJ221 M 220 OHM,J,1/16W 1 R2165,66 ERJ3GEYJ102 M 1KOHM,J,1/16W 2 R2167 ERJ3GEYJ221 M 220 OHM,J,1/16W 1 R2168,69 ERJ3GEYJ472 M 4.7KOHM,J,1/16W 2 R2170-73 ERJ3GEYJ221 M 220 OHM,J,1/16W 4 R2176,77 ERJ3GEYJ221 M 220 OHM,J,1/16W 2 R2181 ERJ3GEY0R00 M 0 OHM, 1/16W 1 R2182,83 ERJ3GEYJ101 M 100 OHM,J,1/16W 2 参考号 部品号 部品名称 & 说明 件数 备注 139 R2184-87 ERJ3GEYJ221 M 220 OHM,J,1/16W 4 R2188 ERJ3GEYJ103 M 10KOHM,J,1/16W 1 R2192,93 ERJ3GEYJ221 M 220 OHM,J,1/16W 2 R2195,96 ERJ3GEYJ104 M 100KOHM,J,1/16W 2 R2197 ERJ3GEYJ471 M 470 OHM,J,1/16W 1 R2202 ERJ3GEYJ101 M 100 OHM,J,1/16W 1 R2203 ERJ6GEYJ101 M 100 OHM,J,1/10W 1 R2204 ERJ6GEYJ561 M 560 OHM,J,1/10W 1 R2208 ERJ6GEYJ471 M 470 OHM,J,1/10W 1 R2209 ERJ3GEYJ332 M 3.3KOHM,J,1/16W 1 R2210 ERJ6GEYJ122 M 1.2KOHM,J,1/10W 1 R2211 ERJ3GEY0R00 M 0 OHM, 1/16W 1 R2213 ERJ3GEYJ103 M 10KOHM,J,1/16W 1 R2214 ERJ3GEYJ332 M 3.3KOHM,J,1/16W 1 R2215 ERJ3GEY0R00 M 0 OHM, 1/16W 1 R2219 ERJ6GEYJ101 M 100 OHM,J,1/10W 1 R2220 ERJ3GEYJ153 M 15KOHM,J,1/16W 1 R2224,25 ERJ3GEY0R00 M 0 OHM, 1/16W 2 R2227 ERJ6GEY0R00 M 0 OHM, 1/10W 1 R2230,31 ERJ3GEYJ104 M 100KOHM,J,1/16W 2 R2232,33 ERJ3GEYJ153 M 15KOHM,J,1/16W 2 R2234-37 ERJ3GEYJ103 M 10KOHM,J,1/16W 4 R2238,39 ERJ3GEY0R00 M 0 OHM, 1/16W 2 R2302 ERJ3GEYJ223 M 22KOHM,J,1/16W 1 R2303 ERJ3GEYJ562 M 5.6KOHM,J,1/16W 1 R2304 ERJ3GEYJ104 M 100KOHM,J,1/16W 1 R2305 ERJ3GEYJ471 M 470 OHM,J,1/16W 1 R2306 ERJ6GEYJ821 M 820 OHM,J,1/10W 1 R2307 ERJ3GEYJ104 M 100KOHM,J,1/16W 1 R2310 ERJ3EKF1301 M 1.3KOHM, 1/16W 1 PA R2310 ERJ3GEYJ184 M 180KOHM,J,1/16W 1 H R2311 ERJ3EKF1301 M 1.3KOHM, 1/16W 1 PA R2311 ERJ6GEYJ182 M 1.8KOHM,J,1/10W 1 H R2312 ERJ3EKF1002 M 10KOHM, 1/16W 1 R2323,24 ERJ3GEY0R00 M 0 OHM, 1/16W 2 R2325 ERJ3GEYJ103 M 10KOHM,J,1/16W 1 R2329 ERJ3EKF1003 M 100KOHM, 1/16W 1 R2332 ERJ3GEYJ103 M 10KOHM,J,1/16W 1 R2338 ERJ3GEY0R00 M 0 OHM, 1/16W 1 R2341 ERJ6GEY0R00 M 0 OHM, 1/10W 1 R2349 ERJ3GEYJ101 M 100 OHM,J,1/16W 1 R2354 ERJ3GEYJ102 M 1KOHM,J,1/16W 1 R2357 ERJ6GEY0R00 M 0 OHM, 1/10W 1 R2359 ERJ3GEYJ222 M 2.2KOHM,J,1/16W 1 R2360 ERJ3GEYJ103 M 10KOHM,J,1/16W 1 R2361 ERJ3GEYJ562 M 5.6KOHM,J,1/16W 1 R2363 ERJ3GEYJ471 M 470 OHM,J,1/16W 1 R2364 ERJ3GEYJ473 M 47KOHM,J,1/16W 1 R2365 ERJ3GEYJ101 M 100 OHM,J,1/16W 1 R2366 ERJ3GEYJ472 M 4.7KOHM,J,1/16W 1 R2368 ERJ6GEY0R00 M 0 OHM, 1/10W 1 R2369 ERJ3GEYJ183 M 18KOHM,J,1/16W 1 R2372,73 ERJ6GEYJ681 M 680 OHM,J,1/10W 2 R2375 ERJ3GEYJ101 M 100 OHM,J,1/16W 1 R2376 ERJ3EKF1002 M 10KOHM, 1/16W 1 R2379,80 ERJ6ENF2201 M 2.2KOHM, 1/10W 2 R2383 ERJ3EKF3301 M 3.3KOHM, 1/16W 1 R2384 ERJ3EKF1151 M1.15KOHM, 1/16W 1 R2387 ERJ3EKF1151 M1.15KOHM, 1/16W 1 R2388 ERJ3EKF3301 M 3.3KOHM, 1/16W 1 PA R2388,89 ERJ6GEYJ102 M 1KOHM,J,1/10W 2 R2390 ERJ3GEYJ203 M 20KOHM,J,1/16W 1 R2391 ERJ3GEYJ103 M 10KOHM,J,1/16W 1 R2392 ERJ3GEYJ223 M 22KOHM,J,1/16W 1 R2393 ERJ3GEYJ103 M 10KOHM,J,1/16W 1 R2396 ERJ3GEYJ103 M 10KOHM,J,1/16W 1 R2397 ERJ3GEYJ473 M 47KOHM,J,1/16W 1 H R2397 ERJ6GEY0R00 M 0 OHM, 1/10W 1 PA R2398 ERJ3GEYJ123 M 12KOHM,J,1/16W 1 H R2398 ERJ6GEY0R00 M 0 OHM, 1/10W 1 PA R2399 ERJ3GEYJ102 M 1KOHM,J,1/16W 1 R2400 ERJ6GEYJ182 M 1.8KOHM,J,1/10W 1 R2401,02 ERJ3GEYJ331 M 330 OHM,J,1/16W 2 R2403 ERJ3GEYJ472 M 4.7KOHM,J,1/16W 1 R2404,05 ERJ3GEYJ331 M 330 OHM,J,1/16W 2 R2406 ERJ3GEYJ472 M 4.7KOHM,J,1/16W 1 R2407 ERJ3EKF1241 M1.24KOHM, 1/16W 1 参考号 部品号 部品名称 & 说明 件数 备注 R2408 ERJ3EKF1071 M1.07KOHM, 1/16W 1 R2409 ERJ3EKF1621 M1.62KOHM, 1/16W 1 R2410 ERJ3EKF7870 M 787 OHM, 1/16W 1 R2421 ERJ3EKF1621 M1.62KOHM, 1/16W 1 R2422 ERJ3EKF7870 M 787 OHM, 1/16W 1 R2512 ERJ6GEYJ470 M 47 OHM,J,1/10W 1 R2516 ERJ3GEYJ223 M 22KOHM,J,1/16W 1 R2517 ERJ6GEYJ470 M 47 OHM,J,1/10W 1 R2520 ERJ3GEYJ224 M 220KOHM,J,1/16W 1 R2521 ERJ6GEYJ470 M 47 OHM,J,1/10W 1 R2524 ERJ3GEYJ223 M 22KOHM,J,1/16W 1 R2525 ERJ3EKF5760 M 576 OHM, 1/16W 1 R2530 ERJ3GEYJ223 M 22KOHM,J,1/16W 1 R2531 ERJ3EKF2700 M 270 OHM, 1/16W 1 R2542 ERJ3GEYJ473 M 47KOHM,J,1/16W 1 R2556,57 ERJ3GEYJ562 M 5.6KOHM,J,1/16W 2 R2558 ERJ6GEY0R00 M 0 OHM, 1/10W 1 R3001-10 ERJ6ENF75R0 M 75 OHM, 1/10W 10 R3011 ERJ3GEY0R00 M 0 OHM, 1/16W 1 R3012 ERJ6ENF75R0 M 75 OHM, 1/10W 1 R3020 ERJ6ENF2202 M 2.2KOHM, 1/10W 1 R3021,22 ERJ3GEYJ103 M 10KOHM,J,1/16W 2 R3027 ERJ6ENF75R0 M 75 OHM, 1/10W 1 R3039 ERJ3GEYJ221 M 220 OHM,J,1/16W 1 R3044,45 ERJ3GEY0R00 M 0 OHM, 1/16W 2 R3048 ERJ3GEYJ223 M 22KOHM,J,1/16W 1 R3049 ERJ3GEYJ221 M 220 OHM,J,1/16W 1 R3050 ERJ3GEYJ242 M 2.4KOHM,J,1/16W 1 R3051 ERJ3GEYJ682 M 6.8KOHM,J,1/16W 1 R3057,58 ERJ3GEY0R00 M 0 OHM, 1/16W 2 R3059,60 ERJ3GEYJ221 M 220 OHM,J,1/16W 2 R3061 ERJ3GEY0R00 M 0 OHM, 1/16W 1 R3062-64 ERJ3GEYJ221 M 220 OHM,J,1/16W 3 R3068 ERJ6ENF75R0 M 75 OHM, 1/10W 1 R3070 ERJ3GEYJ102 M 1KOHM,J,1/16W 1 R3072-75 ERJ3GEYJ221 M 220 OHM,J,1/16W 4 R3076 ERJ3GEY0R00 M 0 OHM, 1/16W 1 R3080 ERJ3GEY0R00 M 0 OHM, 1/16W 1 R3087 ERJ3GEYJ221 M 220 OHM,J,1/16W 1 R3089,90 ERJ3GEYJ220 M 22 OHM,J,1/16W 2 R3092 ERJ3GEYJ221 M 220 OHM,J,1/16W 1 R3094,95 ERJ3GEYJ221 M 220 OHM,J,1/16W 2 R3096 ERJ3GEY0R00 M 0 OHM, 1/16W 1 R3097 ERJ3GEYJ221 M 220 OHM,J,1/16W 1 R3099-01 ERJ3GEYJ221 M 220 OHM,J,1/16W 3 R3102 ERJ3GEYJ682 M 6.8KOHM,J,1/16W 1 R3111-14 ERJ3GEY0R00 M 0 OHM, 1/16W 4 R3115 ERJ3GEYJ101 M 100 OHM,J,1/16W 1 R3118 ERJ3GEYJ101 M 100 OHM,J,1/16W 1 R3119,20 ERJ3EKF91R0 M 91 OHM, 1/16W 2 R3121 ERJ3EKF1300V M 130 OHM, 1/16W 1 R3122 ERJ3GEYJ101 M 100 OHM,J,1/16W 1 R3123 ERJ3EKF1300V M 130 OHM, 1/16W 1 R3125 ERJ6GEYJ102 M 1KOHM,J,1/10W 1 R3126 ERJ3GEYJ101 M 100 OHM,J,1/16W 1 R3127 ERJ6GEYJ102 M 1KOHM,J,1/10W 1 R3134 ERJ3GEYJ104 M 100KOHM,J,1/16W 1 R3135 ERJ3EKF91R0 M 91 OHM, 1/16W 1 R3138 ERJ3EKF1000 M 100 OHM, 1/16W 1 R3139 ERJ6GEYJ102 M 1KOHM,J,1/10W 1 R3140 ERJ3EKF1300V M 130 OHM, 1/16W 1 R3141 ERJ6GEYJ102 M 1KOHM,J,1/10W 1 R3160,61 ERJ6GEYJ102 M 1KOHM,J,1/10W 2 R3167 ERJ3GEYJ102 M 1KOHM,J,1/16W 1 R3174-76 ERJ3GEYJ221 M 220 OHM,J,1/16W 3 R3206 ERJ3GEYJ101 M 100 OHM,J,1/16W 1 R3213,14 ERJ3GEY0R00 M 0 OHM, 1/16W 2 R3215 J0JCC0000241 片状电感 1 R3219 ERJ3GEYJ101 M 100 OHM,J,1/16W 1 R3222 ERJ3GEY0R00 M 0 OHM, 1/16W 1 R3224 ERJ3GEY0R00 M 0 OHM, 1/16W 1 R3227-29 ERJ3GEY0R00 M 0 OHM, 1/16W 3 R3233,34 ERJ6ENF75R0 M 75 OHM, 1/10W 2 R3238 ERJ3GEY0R00 M 0 OHM, 1/16W 1 R3239-42 ERJ3GEYJ103 M 10KOHM,J,1/16W 4 R3250,51 ERJ3GEY0R00 M 0 OHM, 1/16W 2 R3253 ERJ3GEYJ221 M 220 OHM,J,1/16W 1 参考号 部品号 部品名称 & 说明 件数 备注 140 R3254 ERJ6GEY0R00 M 0 OHM, 1/10W 1 R3255 ERJ6GEYJ561 M 560 OHM,J,1/10W 1 R3256 ERJ3GEY0R00 M 0 OHM, 1/16W 1 R3259 ERJ3GEYJ221 M 220 OHM,J,1/16W 1 R3261-64 ERJ3GEY0R00 M 0 OHM, 1/16W 4 R3266,67 ERJ3GEY0R00 M 0 OHM, 1/16W 2 R3278,79 ERJ3GEY0R00 M 0 OHM, 1/16W 2 R3281 ERJ3GEY0R00 M 0 OHM, 1/16W 1 R3283,84 ERJ3GEY0R00 M 0 OHM, 1/16W 2 R3286 J0JCC0000241 片状电感 1 R3290,91 ERJ3GEYJ472 M 4.7KOHM,J,1/16W 2 R3302 ERJ6GEYJ101 M 100 OHM,J,1/10W 1 R3305 ERJ6GEYJ101 M 100 OHM,J,1/10W 1 R3306,07 ERJ6GEYJ472 M 4.7KOHM,J,1/10W 2 R3308,09 ERJ6GEY0R00 M 0 OHM, 1/10W 2 R3310 ERJ6ENF75R0 M 75 OHM, 1/10W 1 R3312 ERJ3GEYJ103 M 10KOHM,J,1/16W 1 R3313 ERJ6ENF75R0 M 75 OHM, 1/10W 1 R3317 ERJ3GEYJ103 M 10KOHM,J,1/16W 1 R3318 ERJ6ENF75R0 M 75 OHM, 1/10W 1 R3320 ERJ6GEY0R00 M 0 OHM, 1/10W 1 R3323,24 ERJ6GEY0R00 M 0 OHM, 1/10W 2 R3330 ERJ3GEY0R00 M 0 OHM, 1/16W 1 R3336 ERJ3GEYJ473 M 47KOHM,J,1/16W 1 R3337 ERJ3GEYJ183 M 18KOHM,J,1/16W 1 R3338 ERJ3GEYJ101 M 100 OHM,J,1/16W 1 R3339 ERJ3GEYJ471 M 470 OHM,J,1/16W 1 R3340 ERJ3GEYJ101 M 100 OHM,J,1/16W 1 R3341 ERJ3GEYJ473 M 47KOHM,J,1/16W 1 R3342 ERJ3GEYJ183 M 18KOHM,J,1/16W 1 R3343 ERJ3GEYJ471 M 470 OHM,J,1/16W 1 R3344 ERJ3GEYJ101 M 100 OHM,J,1/16W 1 R3345 ERJ3GEYJ183 M 18KOHM,J,1/16W 1 R3346 ERJ3GEYJ473 M 47KOHM,J,1/16W 1 R3347 ERJ3GEYJ471 M 470 OHM,J,1/16W 1 R3348,49 ERJ3GEYJ680 M 68 OHM,J,1/16W 2 R3350-52 ERJ3GEYJ510 M 51 OHM,J,1/16W 3 R3353 ERJ3EKF2703 M 270KOHM, 1/16W 1 R3354 ERJ3EKF1503 M 150KOHM, 1/16W 1 R3408,09 ERJ3GEYJ361 M 360 OHM,J,1/16W 2 R3704 ERJ3GEY0R00 M 0 OHM, 1/16W 1 R3709-11 ERJ3GEY0R00 M 0 OHM, 1/16W 3 R3714 ERJ3GEY0R00 M 0 OHM, 1/16W 1 R3716,17 ERJ6GEYJ184 M 180KOHM,J,1/10W 2 R3721 ERJ6GEYJ103 M 10KOHM,J,1/10W 1 R3732 ERJ3GEY0R00 M 0 OHM, 1/16W 1 R3733 ERJ6GEY0R00 M 0 OHM, 1/10W 1 R3736-41 ERJ3GEY0R00 M 0 OHM, 1/16W 6 R3746 ERJ6GEY0R00 M 0 OHM, 1/10W 1 R3748 ERJ6GEY0R00 M 0 OHM, 1/10W 1 R3750 ERJ6GEY0R00 M 0 OHM, 1/10W 1 R3751 ERJ6ENF1432 M14.3KOHM, 1/10W 1 R3753 ERJ6ENF1741 M1.74KOHM, 1/10W 1 R3754 ERJ6ENF1621 M1.62KOHM, 1/10W 1 R3755 ERJ6GEY0R00 M 0 OHM, 1/10W 1 R3757 ERJ6GEY0R00 M 0 OHM, 1/10W 1 R3758 ERJ6ENF6651 M6.65KOHM, 1/10W 1 R3759-64 ERJ6GEY0R00 M 0 OHM, 1/10W 6 R3765 ERJ6ENF2321 M2.32KOHM, 1/10W 1 R3767 ERJ6ENF3161 M3.16KOHM, 1/10W 1 R3768 ERJ6GEY0R00 M 0 OHM, 1/10W 1 R4001 ERJ3EKF1211 M1.21KOHM, 1/16W 1 R4004 ERJ2GE0R00 M 0.0 OHM, J,0.063W 1 R4008 ERJ2GE0R00 M 0.0 OHM, J,0.063W 1 R4010 ERJ2GE0R00 M 0.0 OHM, J,0.063W 1 R4018 ERJ2GEJ103 M 10KOHM, J,0.063W 1 R4019 ERJ2GE0R00 M 0.0 OHM, J,0.063W 1 R4021 ERJ2GE0R00 M 0.0 OHM, J,0.063W 1 R4022 ERJ2GEJ102 M 1KOHM, J,0.063W 1 R4024,25 ERJ2GE0R00 M 0.0 OHM, J,0.063W 2 R4026,27 ERJ2GEJ102 M 1KOHM, J,0.063W 2 R4029 ERJ2GEJ220 M 22 OHM, J,0.063W 1 R4031-33 ERJ2GEJ103 M 10KOHM, J,0.063W 3 R4037-39 D1HG1038A002 排阻 3 R4040,41 ERJ2GE0R00 M 0.0 OHM, J,0.063W 2 R4045,46 ERJ3GEY0R00 M 0 OHM, 1/16W 2 R4101 ERJ2GEJ103 M 10KOHM, J,0.063W 1 参考号 部品号 部品名称 & 说明 件数 备注 R4257 ERJ3EKF3302 M 33KOHM, 1/16W 1 R4265 ERJ3EKF3242 M32.4KOHM, 1/16W 1 R4269 ERJ2GE0R00 M 0.0 OHM, J,0.063W 1 R4271,72 ERJ2GE0R00 M 0.0 OHM, J,0.063W 2 R4286,87 ERJ2GE0R00 M 0.0 OHM, J,0.063W 2 R4293 ERJ2GE0R00 M 0.0 OHM, J,0.063W 1 R4338-43 ERJ2GE0R00 M 0.0 OHM, J,0.063W 6 R4457 ERJ2GE0R00 M 0.0 OHM, J,0.063W 1 R4465 ERJ2GEJ224 M 220KOHM, J,0.063W 1 R4469,70 ERJ3EKF1500 M 150 OHM, 1/16W 2 R4474 ERJ3EKF1211 M1.21KOHM, 1/16W 1 R4479,80 ERJ3EKF4220 M 422 OHM, 1/10W 2 R4481 ERJ3EKF2201 M 2.2KOHM, 1/16W 1 R4482,83 ERJ3EKF1781 M1.78KOHM, 1/16W 2 R4486 ERJ3EKF4870 M 487 OHM, 1/16W 1 R4487 ERJ3EKF5600 M 560 OHM, 1/16W 1 R4488 ERJ3EKF2201 M 2.2KOHM, 1/16W 1 R4490 ERJ6GEYJ102 M 1KOHM,J,1/10W 1 R4492 ERJ6GEYJ102 M 1KOHM,J,1/10W 1 R4495 ERJ3EKF4302 M 43KOHM, 1/16W 1 R4496-99 ERJ6GEYJ102 M 1KOHM,J,1/10W 4 R4500 ERJ3EKF2702V M27.0KOHM, 1/16W 1 R4501,02 ERJ6GEYJ102 M 1KOHM,J,1/10W 2 R4503 ERJ3EKF1600 M 160 OHM, 1/16W 1 R4507,08 ERJ2GE0R00 M 0.0 OHM, J,0.063W 2 R4510 ERJ2GE0R00 M 0.0 OHM, J,0.063W 1 R4517 ERJ3EKF1371 M 13.7 OHM, 1/16W 1 R4520 ERJ3EKF1691 M1.69KOHM, 1/16W 1 R4521,22 ERJ2GEJ220 M 22 OHM, J,0.063W 2 R4527 ERJ2GEJ220 M 22 OHM, J,0.063W 1 R4533 ERJ2GEJ220 M 22 OHM, J,0.063W 1 R4534,35 ERJ2GEJ101 M 100 OHM, J,0.063W 2 R4544 ERJ2GEJ220 M 22 OHM, J,0.063W 1 R4550 EXB28V220J 电阻阵列 1 R4552 EXB28V220J 电阻阵列 1 R4554 ERJ2GEJ220 M 22 OHM, J,0.063W 1 R4555 EXB28V220J 电阻阵列 1 R4560,61 EXB28V220J 电阻阵列 2 R4563-65 ERJ2GEJ220 M 22 OHM, J,0.063W 3 R4568 ERJ2GEJ101 M 100 OHM, J,0.063W 1 R4572 ERJ2GEJ103 M 10KOHM, J,0.063W 1 R4575 ERJ2GEJ472 M 4.7KOHM, J,0.063W 1 R4577-79 ERJ2GEJ222 M 2.2KOHM, J,0.063W 3 R4583,84 ERJ2GEJ390 M 39 OHM, J,0.063W 2 R4589-04 ERJ2GEJ2R7X M 2.7OHM, J,0.063W 16 R4605,06 ERJ2GEJ103 M 10KOHM, J,0.063W 2 R4607 ERJ2GEJ220 M 22 OHM, J,0.063W 1 R4609,10 ERJ2GEJ103 M 10KOHM, J,0.063W 2 R4612,13 ERJ2GEJ472 M 4.7KOHM, J,0.063W 2 R4617,18 ERJ2GEJ472 M 4.7KOHM, J,0.063W 2 R4619 ERJ2GEJ473 M 47KOHM,J,0.063W 1 R4620 ERJ2GEJ560 M 56 OHM, J,0.063W 1 R4621 ERJ2GEJ473 M 47KOHM,J,0.063W 1 R4622 ERJ2GEJ560 M 56 OHM, J,0.063W 1 R4624 ERJ2GEJ560 M 56 OHM, J,0.063W 1 R4626 ERJ2GEJ560 M 56 OHM, J,0.063W 1 R4628 ERJ2GEJ103 M 10KOHM, J,0.063W 1 R4629-32 ERJ2GEJ472 M 4.7KOHM, J,0.063W 4 R4633,34 ERJ2GEJ220 M 22 OHM, J,0.063W 2 R4636 ERJ2GEJ103 M 10KOHM, J,0.063W 1 R4637 ERJ2GEJ330 M 33 OHM, J,0.063W 1 R4639 ERJ2GEJ103 M 10KOHM, J,0.063W 1 R4640 ERJ2GEJ220 M 22 OHM, J,0.063W 1 R4641 EXB28V330J 电阻阵列 1 R4642-45 ERJ2GEJ220 M 22 OHM, J,0.063W 4 R4647 ERJ2GEJ220 M 22 OHM, J,0.063W 1 R4648 ERJ2GEJ330 M 33 OHM, J,0.063W 1 R4655 ERJ2GEJ330 M 33 OHM, J,0.063W 1 R4657 ERJ2GEJ182 M 1.8KOHM, J,0.063W 1 R4658 ERJ2GEJ220 M 22 OHM, J,0.063W 1 R4660 ERJ2GEJ220 M 22 OHM, J,0.063W 1 R4661 ERJ2GEJ472 M 4.7KOHM, J,0.063W 1 R4662 ERJ2GEJ220 M 22 OHM, J,0.063W 1 R4665 EXB2HV220JV 电阻阵列 1 R4667 EXB2HV220JV 电阻阵列 1 R4668 ERJ2GEJ680 M 68 OHM, J,0.063W 1 R4669 EXB2HV220JV 电阻阵列 1 参考号 部品号 部品名称 & 说明 件数 备注 141 R4672,73 ERJ2GEJ103 M 10KOHM, J,0.063W 2 R4675 ERJ3EKF1802 M 18KOHM, 1/16W 1 R4677 ERJ3EKF1802 M 18KOHM, 1/16W 1 R4679,80 ERJ3EKF2202 M 22KOHM, 1/16W 2 R4681,82 ERJ3EKF3302 M 33KOHM, 1/16W 2 R4701 ERJ2GEJ680 M 68 OHM, J,0.063W 1 R4706 ERJ2GE0R00 M 0.0 OHM, J,0.063W 1 R4708,09 ERJ2GEJ680 M 68 OHM, J,0.063W 2 R4710 ERJ2GE0R00 M 0.0 OHM, J,0.063W 1 R4711 ERJ2GEJ103 M 10KOHM, J,0.063W 1 R4712 ERJ2GE0R00 M 0.0 OHM, J,0.063W 1 R4713,14 EXB2HV221JV 电阻阵列 2 R4715 ERJ2GE0R00 M 0.0 OHM, J,0.063W 1 R4718-20 ERJ2GEJ680 M 68 OHM, J,0.063W 3 R4727 ERJ2GE0R00 M 0.0 OHM, J,0.063W 1 R4729,30 ERJ3EKF1000 M 100 OHM, 1/16W 2 R4731 ERJ3EKF1001 M 1KOHM, 1/16W 1 R4732 ERJ3EKF4751 M 4.75KOHM, 1/16W 1 R4733 ERJ3EKF75R0 M 0.75HM, 1/16W 1 R4734 ERJ2GEJ223 M 22KOHM, J,0.063W 1 R4735 ERJ3EKF2001 M 2KOHM, 1/16W 1 R4737 ERJ2GE0R00 M 0.0 OHM, J,0.063W 1 R4738,39 ERJ2GEJ332 M 3.3KOHM, J,0.063W 2 R4743-47 ERJ2GEJ680 M 68 OHM, J,0.063W 5 R4749,50 EXB2HV680J 电阻阵列 2 R4751-54 ERJ2GEJ220 M 22 OHM, J,0.063W 4 R4756-60 ERJ2GEJ680 M 68 OHM, J,0.063W 5 R4762 EXB2HV680J 电阻阵列 1 R4763-65 ERJ2GE0R00 M 0.0 OHM, J,0.063W 3 R4772 EXB2HV470JV 电阻阵列 1 R4773 ERJ2GEJ470 M 47 OHM, J,0.063W 1 R4774 EXB2HV470JV 电阻阵列 1 R4775 ERJ2GEJ470 M 47 OHM, J,0.063W 1 R4776 EXB2HV470JV 电阻阵列 1 R4777 ERJ2GEJ470 M 47 OHM, J,0.063W 1 R4778 EXB2HV470JV 电阻阵列 1 R4779 ERJ2GEJ470 M 47 OHM, J,0.063W 1 R4782 ERJ2GEJ220 M 22 OHM, J,0.063W 1 R4783 ERJ2GEJ472 M 4.7KOHM, J,0.063W 1 R4784 ERJ2GEJ220 M 22 OHM, J,0.063W 1 R4785 ERJ2GEJ472 M 4.7KOHM, J,0.063W 1 R4788 EXB2HV470JV 电阻阵列 1 R4791,92 ERJ2GEJ470 M 47 OHM, J,0.063W 2 R4793,94 ERJ2GEJ220 M 22 OHM, J,0.063W 2 R4796 EXB2HV470JV 电阻阵列 1 R4804 ERJ2GEJ101 M 100 OHM, J,0.063W 1 R4805,06 ERJ3EKF1001 M 1KOHM, 1/16W 2 R4807-11 ERJ2GE0R00 M 0.0 OHM, J,0.063W 5 R4814 ERJ2GEJ103 M 10KOHM, J,0.063W 1 R4816,17 ERJ2GEJ223 M 22KOHM, J,0.063W 2 R4819 ERJ2GEJ223 M 22KOHM, J,0.063W 1 R4822 ERJ2GEJ103 M 10KOHM, J,0.063W 1 R4823-25 J0JAD0000025 片状电感 3 R4837 ERJ2GEJ220 M 22 OHM, J,0.063W 1 R4838 ERJ2GEJ112 M 1.1KOHM, J,0.063W 1 R4891 ERJ2GE0R00 M 0.0 OHM, J,0.063W 1 R4898 ERJ2GEJ103 M 10KOHM, J,0.063W 1 R4960 EXB2HV680J 电阻阵列 1 R4961-63 ERJ2GEJ680 M 68 OHM, J,0.063W 3 R4964 EXB2HV680J 电阻阵列 1 R4965,66 ERJ2GEJ680 M 68 OHM, J,0.063W 2 R4967 EXB2HV680J 电阻阵列 1 R4968-72 ERJ2GEJ680 M 68 OHM, J,0.063W 5 R5601 ERJ3EKF1800 M 180 OHM, 1/16W 1 R5602 ECJ1VB1E104K C 0.10UF, K, 25V 1 R5603 ERJ3EKF1542 M15.4KOHM, 1/16W 1 R5605 ERJ3GEYJ472 M 4.7KOHM,J,1/16W 1 R5606 ERJ3GEYJ222 M 2.2KOHM,J,1/16W 1 R5607 ERJ3EKF4531 M4.53KOHM, 1/16W 1 R5609 ERJ3EKF2000 M 200 OHM, 1/16W 1 R5610 ECJ1VB1H472K C 4700PF, K, 50V 1 R5611 ERJ6ENF8202 M 82KOHM, 1/10W 1 R5612 ERJ6ENF1602 M 16KOHM, 1/10W 1 R5615 ERJ3GEYJ103 M 10KOHM,J,1/16W 1 R5617 ERJ3GEYJ102 M 1KOHM,J,1/16W 1 R5619 ERJ3GEYJ333 M 33KOHM,J,1/16W 1 R5620 ERJ3GEYJ102 M 1KOHM,J,1/16W 1 参考号 部品号 部品名称 & 说明 件数 备注 R5621 ERJ3GEYJ472 M 4.7KOHM,J,1/16W 1 R5625-27 ERJ3GEYJ472 M 4.7KOHM,J,1/16W 3 R5632 ERJ3GEYJ471 M 470 OHM,J,1/16W 1 R5633 ERJ3GEYJ102 M 1KOHM,J,1/16W 1 R5634 ERJ3GEYJ471 M 470 OHM,J,1/16W 1 R5635 ERJ3GEYJ221 M 220 OHM,J,1/16W 1 R5637,38 ERJ3GEYJ103 M 10KOHM,J,1/16W 2 R5639 ERJ3GEYJ222 M 2.2KOHM,J,1/16W 1 R5640 ERJ3GEYJ472 M 4.7KOHM,J,1/16W 1 R5641 ERJ3GEYJ222 M 2.2KOHM,J,1/16W 1 R5642 ERJ3GEYJ471 M 470 OHM,J,1/16W 1 R5643 ERJ3GEYJ102 M 1KOHM,J,1/16W 1 R5644 ERJ3GEYJ222 M 2.2KOHM,J,1/16W 1 R5645 ERJ3EKF2201 M 2.2KOHM, 1/16W 1 R5646 ERJ3EKF4701 M 4.7KOHM, 1/16W 1 R5647 ERJ3GEYJ221 M 220 OHM,J,1/16W 1 R5648 ERJ3GEYJ392 M 3.9KOHM,J,1/16W 1 R5649 ERJ3GEYJ104 M 100KOHM,J,1/16W 1 R5650 ERJ3GEYJ221 M 220 OHM,J,1/16W 1 R5652 ERJ3GEY0R00 M 0 OHM, 1/16W 1 R5653,54 ERJ3GEYJ103 M 10KOHM,J,1/16W 2 R5659 ERJ3EKF4700 M 470 OHM, 1/16W 1 R5660 ERJ3GEY0R00 M 0 OHM, 1/16W 1 R5662 ERJ3GEYJ472 M 4.7KOHM,J,1/16W 1 R5664 ERJ3GEYJ472 M 4.7KOHM,J,1/16W 1 R5665 ERJ3GEYJ473 M 47KOHM,J,1/16W 1 R5667-69 ERJ3GEYJ473 M 47KOHM,J,1/16W 3 R5672 ERJ3GEYJ103 M 10KOHM,J,1/16W 1 R5676 ERJ3GEYJ103 M 10KOHM,J,1/16W 1 R5692 ERJ3GEYJ102 M 1KOHM,J,1/16W 1 R5693 ERJ3GEYJ333 M 33KOHM,J,1/16W 1 R5694 ERJ3GEYJ473 M 47KOHM,J,1/16W 1 R5695 ERJ3GEYJ103 M 10KOHM,J,1/16W 1 R5801 ERJ3EKF8450 M 845 OHM, 1/16W 1 R5802 ERJ3EKF1302 M 13KOHM, 1/16W 1 R5803 ERJ3EKF2001 M 2KOHM, 1/16W 1 R5804 ERJ3GEY0R00 M 0 OHM, 1/16W 1 R5805-08 ERJ3GEYJ222 M 2.2KOHM,J,1/16W 4 R5809 ERJ3GEYJ472 M 4.7KOHM,J,1/16W 1 R5822-24 ERJ3GEYJ101 M 100 OHM,J,1/16W 3 R5826 ERJ3GEYJ101 M 100 OHM,J,1/16W 1 R5836 ERJ3GEYJ102 M 1KOHM,J,1/16W 1 R6001-06 ERJ14YJ150U M 15 OHM, J,1/4W 6 R6020 ERG3FJS101D M 100 OHM, J, 3W 1 R6021 ERJ14YJ150U M 15 OHM, J,1/4W 1 R6022 ERG3FJS101D M 100 OHM, J, 3W 1 R6023-27 ERJ14YJ150U M 15 OHM, J,1/4W 5 R6031,32 ERJ6ENF8202 M 82KOHM, 1/10W 2 R6033 ERJ6ENF5602 M 56KOHM, 1/10W 1 R6034 ERJ6ENF2702 M 27KOHM, 1/10W 1 R6041-44 ERJ14YJ100 M 10 OHM, J,1/4W 4 R6051-54 ERJ14YJ100 M 10 OHM, J,1/4W 4 R6061,62 ERJ6GEYJ224 M 220KOHM,J,1/10W 2 R6101-08 ERJ6GEYJ101 M 100 OHM,J,1/10W 8 R6109 D0GD100JA036 M 10 OHM,J,0.25W 1 R6110 ERJ6GEYJ103 M 10KOHM,J,1/10W 1 R6111,12 D0GD470JA036 M 47 OHM,J,0.25W 2 R6113 ERJ14YJ224 M 220KOHM, J,1/4W 1 R6114 D0GD470JA036 M 47 OHM,J,0.25W 1 R6116 ERJ6GEYJ103 M 10KOHM,J,1/10W 1 R6131,32 ERJ6GEYJ101 M 100 OHM,J,1/10W 2 R6133,34 ERJ6GEYJ151 M 150 OHM,J,1/10W 2 R6135,36 D0GD100JA036 M 10 OHM,J,0.25W 2 R6141,42 ERJ6GEYJ103 M 10KOHM,J,1/10W 2 R6146,47 ERJ6GEYJ103 M 10KOHM,J,1/10W 2 R6151,52 ERJ6GEYJ101 M 100 OHM,J,1/10W 2 R6153,54 ERJ6GEYJ151 M 150 OHM,J,1/10W 2 R6155,56 ERJ6GEY0R00 M 0 OHM, 1/10W 2 R6157-60 D0GF1R0JA047 M 1.0 OHM,J, 0.33W 4 R6171 D0GD100JA036 M 10 OHM,J,0.25W 1 R6172,73 ERJ6GEYJ103 M 10KOHM,J,1/10W 2 R6181 D0GD100JA036 M 10 OHM,J,0.25W 1 R6182,83 ERJ6GEYJ103 M 10KOHM,J,1/10W 2 R6191-94 ERJ6GEYJ101 M 100 OHM,J,1/10W 4 R6195 D0GD104JA036 M 100KOHM,J,0.25W 1 R6196 ERJ6GEYJ104 M 100KOHM,J,1/10W 1 R6213 ERJ6GEYJ101 M 100 OHM,J,1/10W 1 参考号 部品号 部品名称 & 说明 件数 备注 142 R6214 D0GD151JA036 M 150 OHM,J,0.25W 1 R6222 ERG1FJS103D M 10KOHM, J, 1W 1 R6223 ERG2FJS123D M 12KOHM, J, 2W 1 R6225 D0GD203JA036 M 20KOHM,J,0.25W 1 R6226 ERJ6GEYJ163V M 16KOHM,J,1/10W 1 R6227 ERJ6GEYJ163 M 16KOHM,J,1/10W 1 R6228 ERJ6GEYJ562 M 5.6KOHM,J,1/10W 1 R6229 ERJ6GEYJ163 M 16KOHM,J,1/10W 1 R6231 ERJ6GEY0R00 M 0 OHM, 1/10W 1 R6232 ERJ6ENF1201 M 1.2KOHM, 1/10W 1 R6241 EXB38V470J 电阻阵列 1 R6242 EXB38V472J 电阻阵列 1 R6243 ERJ6GEYJ470 M 47 OHM,J,1/10W 1 R6244 ERJ6GEYJ472 M 4.7KOHM,J,1/10W 1 R6245 ERJ6GEYJ470 M 47 OHM,J,1/10W 1 R6246 ERJ6GEYJ472 M 4.7KOHM,J,1/10W 1 R6251 D0GD103JA036 M 10KOHM,J,0.25W 1 R6252,53 ERJ6ENF3902 M 39KOHM, 1/10W 2 R6254 ERJ6ENF8201 M 8.2KOHM, 1/10W 1 R6255 ERJ6ENF1201 M 1.2KOHM, 1/10W 1 R6256 ERJ6ENF1501 M 1.5KOHM, 1/10W 1 R6257 ERJ6GEYJ103 M 10KOHM,J,1/10W 1 R6258 ERJ6GEYJ222 M 2.2KOHM,J,1/10W 1 R6261 ERJ6GEYJ104 M 100KOHM,J,1/10W 1 R6401-06 ERJ14YJ150U M 15 OHM, J,1/4W 6 R6421-26 ERJ14YJ150U M 15 OHM, J,1/4W 6 R6441-44 ERJ14YJ100 M 10 OHM, J,1/4W 4 R6451-54 ERJ14YJ100 M 10 OHM, J,1/4W 4 R6465 ERJ6ENF2702 M 27KOHM, 1/10W 1 R6466 ERJ6ENF5602 M 56KOHM, 1/10W 1 R6467,68 ERJ6ENF8202 M 82KOHM, 1/10W 2 R6471 ERJ6GEYJ392 M 3.9KOHM,J,1/10W 1 R6472 ERJ6GEYJ222 M 2.2KOHM,J,1/10W 1 R6473 ERJ6GEYJ561 M 560 OHM,J,1/10W 1 R6474 ERJ6GEYJ102 M 1KOHM,J,1/10W 1 R6475,76 ERJ6GEYJ472 M 4.7KOHM,J,1/10W 2 R6477 ERJ6GEYJ102 M 1KOHM,J,1/10W 1 R6478 ERJ6GEYJ472 M 4.7KOHM,J,1/10W 1 R6479 ERJ6GEYJ104 M 100KOHM,J,1/10W 1 R6501,02 ERJ6GEYJ101 M 100 OHM,J,1/10W 2 R6503 D0GD100JA036 M 10 OHM,J,0.25W 1 R6504,05 ERJ6GEYJ151 M 150 OHM,J,1/10W 2 R6506 D0GD100JA036 M 10 OHM,J,0.25W 1 R6507-09 D0GF1R0JA047 M 1.0 OHM,J, 0.33W 3 R6511,12 ERJ6GEYJ103 M 10KOHM,J,1/10W 2 R6516,17 ERJ6GEYJ103 M 10KOHM,J,1/10W 2 R6521,22 ERJ6GEYJ101 M 100 OHM,J,1/10W 2 R6523,24 ERJ6GEYJ151 M 150 OHM,J,1/10W 2 R6525,26 ERJ6GEY0R00 M 0 OHM, 1/10W 2 R6531 D0GD100JA036 M 10 OHM,J,0.25W 1 R6532,33 ERJ6GEYJ103 M 10KOHM,J,1/10W 2 R6551 D0GD100JA036 M 10 OHM,J,0.25W 1 R6552,53 ERJ6GEYJ103 M 10KOHM,J,1/10W 2 R6561-64 EXB38V470J 电阻阵列 4 R6565-68 EXB38V472J 电阻阵列 4 R6581 D0GD103JA036 M 10KOHM,J,0.25W 1 R6582,83 ERJ6ENF3902 M 39KOHM, 1/10W 2 R6584 ERJ6ENF1002 M 10KOHM, 1/10W 1 R6585 ERJ6ENF1201 M 1.2KOHM, 1/10W 1 R6586 ERJ6ENF1801 M 1.8KOHM, 1/10W 1 R6587 ERJ6GEYJ222 M 2.2KOHM,J,1/10W 1 R6588 ERJ6GEYJ103 M 10KOHM,J,1/10W 1 R6590 ERJ6GEYJ221 M 220 OHM,J,1/10W 1 R6591 EXB38V472J 电阻阵列 1 R6592 ERJ6GEYJ472 M 4.7KOHM,J,1/10W 1 R6603 ERJ6GEYJ101 M 100 OHM,J,1/10W 1 R6604 D0GD151JA036 M 150 OHM,J,0.25W 1 R6605 ERJ6GEYJ104 M 100KOHM,J,1/10W 1 R6606 ERJ6GEY0R00 M 0 OHM, 1/10W 1 R6607 ERJ6ENF5111 M5.11KOHM, 1/10W 1 R6608,09 D0GF102JA047 M 1.0 KOHM,J,0.33W 2 R6610 ERJ6GEYJ104 M 100KOHM,J,1/10W 1 R6611 ERJ6GEYJ105 M 1MOHM,J,1/10W 1 R6612 ERJ6GEYJ470 M 47 OHM,J,1/10W 1 R6613 ERJ6GEYJ105 M 1MOHM,J,1/10W 1 R6614,15 D0GF243JA047 M 24 KOHM,J,0.33W 2 R6616 ERJ6ENF1502 M 15KOHM, 1/10W 1 参考号 部品号 部品名称 & 说明 件数 备注 R6617 ERJ6GEYJ105 M 1MOHM,J,1/10W 1 R6618 ERJ6ENF1202 M 12KOHM, 1/10W 1 R6619 ERJ6ENF1501 M 1.5KOHM, 1/10W 1 R6620 D0D28R2JA021 M 8.2 OHM,J,2W 1 R6621,22 ERJ6GEYJ221 M 220 OHM,J,1/10W 2 R6641,42 ERJ6GEYJ100 M 10 OHM,J,1/10W 2 R6644,45 ERJ6GEYJ100 M 10 OHM,J,1/10W 2 R6647,48 ERJ6GEYJ100 M 10 OHM,J,1/10W 2 R6658 D0D1101JA009 M 100 OHM,J,1W 1 R6659,60 ERJ6GEYJ224 M 220KOHM,J,1/10W 2 R6661 ERJ6GEYJ104 M 100KOHM,J,1/10W 1 R6662 ERJ6ENF3001 M 3KOHM, 1/10W 1 R6663 ERJ6GEYJ103 M 10KOHM,J,1/10W 1 R6664 D0GF222JA047 M 2.2 KOHM,J,0.33W 1 R6665 ERJ14YJ470 M 47 OHM,J, 1/2W 1 R6666 ERJ6GEYJ104 M 100KOHM,J,1/10W 1 R6667,68 ERJ6GEYJ472 M 4.7KOHM,J,1/10W 2 R6671 ERJ6GEYJ470 M 47 OHM,J,1/10W 1 R6672 ERJ6GEYJ103 M 10KOHM,J,1/10W 1 R6673,74 D0GD5R6JA059 M 5.6 OHM,J,0.25W 2 R6682 ERJ6GEYJ101 M 100 OHM,J,1/10W 1 R6683 D0GD151JA036 M 150 OHM,J,0.25W 1 R6684 ERJ6GEYJ100 M 10 OHM,J,1/10W 1 R6685 ERJ6GEYJ471 M 470 OHM,J,1/10W 1 R6686 ERJ6GEYJ103 M 10KOHM,J,1/10W 1 R6687 ERJ6GEYJ222 M 2.2KOHM,J,1/10W 1 R6688 ERJ6GEYJ472 M 4.7KOHM,J,1/10W 1 R6689 ERJ6GEYJ100 M 10 OHM,J,1/10W 1 R6690 ERJ6GEYJ151 M 150 OHM,J,1/10W 1 R6691 ERJ6GEYJ103 M 10KOHM,J,1/10W 1 R6696,97 D0D32R2JA020 M 2.2 OHM,J,3W 2 R6700-08 ERJ6GEYJ471 M 470 OHM,J,1/10W 9 R6710-18 ERJ6GEYJ222 M 2.2KOHM,J,1/10W 9 R6721,22 EXB38V220J 电阻阵列 2 R6723 ERJ6GEYJ222 M 2.2KOHM,J,1/10W 1 R6724 ERJ6GEYJ101 M 100 OHM,J,1/10W 1 R6742 ERJ6GEYJ103 M 10KOHM,J,1/10W 1 R6743 ERJ6GEYJ102 M 1KOHM,J,1/10W 1 R6744 ERJ6GEYJ103 M 10KOHM,J,1/10W 1 R6745 ERJ6GEYJ472 M 4.7KOHM,J,1/10W 1 R6746,47 D0GD103JA036 M 10KOHM,J,0.25W 2 R6755 ERJ6GEYJ101 M 100 OHM,J,1/10W 1 R6756-58 D0GD101JA059 M 100 OHM,J,0.25W 3 R6759 ERJ6GEYJ472 M 4.7KOHM,J,1/10W 1 R6760 ERJ6GEYJ122 M 1.2KOHM,J,1/10W 1 R6761 ERJ6GEYJ100 M 10 OHM,J,1/10W 1 R6762 ERJ6GEYJ103 M 10KOHM,J,1/10W 1 R6775,76 ERJ6GEYJ101 M 100 OHM,J,1/10W 2 R6777 D0GD151JA036 M 150 OHM,J,0.25W 1 R6781 ERJ6GEYJ470 M 47 OHM,J,1/10W 1 R6782 ERJ6GEYJ103 M 10KOHM,J,1/10W 1 R6791 ERJ6GEYJ102 M 1KOHM,J,1/10W 1 R6792 ERJ6GEYJ103 M 10KOHM,J,1/10W 1 R6793 ERJ6GEYJ101 M 100 OHM,J,1/10W 1 R6801,02 ERX1FJSR22D M0.22 OHM, J, 1W 2 R6806 ERJ6GEYJ103 M 10KOHM,J,1/10W 1 R6807 ERJ6GEYJ332 M 3.3KOHM,J,1/10W 1 R6808 ERG3FJS560D M 56 OHM, J, 3W 1 R6809 ERJ6GEYJ103 M 10KOHM,J,1/10W 1 R6810,11 ERJ6GEYJ473 M 47KOHM,J,1/10W 2 R6812 ERJ6ENF2403 M 240KOHM, 1/10W 1 R6813 ERJ6ENF1002 M 10KOHM, 1/10W 1 R6814 ERJ6ENF5601 M 5.6KOHM, 1/10W 1 R6815 ERG2FJS183D M 18KOHM, J, 2W 1 R6816 ERJ6ENF5361 M 5.36KOHM, 1/10W 1 R6817 ERJ6ENF2701 M 2.7KOHM, 1/10W 1 R6821 ERG2FJS221D M 220 OHM, J, 2W 1 R6822 ERJ12YJ104U M 100KOHM, 1/2W 1 R6823 ERG1FJS104D M 100KOHM, J, 1W 1 R6824 ERJ6GEYJ562 M 5.6KOHM,J,1/10W 1 R6825,26 ERJ6ENF2703 M 270KOHM, 1/10W 2 R6827 ERJ6GEY0R00 M 0 OHM, 1/10W 1 R6828 ERJ6ENF5231 M5.23KOHM, 1/10W 1 R6829,30 ERJ6GEYJ224 M 220KOHM,J,1/10W 2 R6831 ERJ6GEYJ153 M 15KOHM,J,1/10W 1 R6833-35 ERJ6ENF5602 M 56KOHM, 1/10W 3 R6836 ERJ6ENF6802 M 68KOHM, 1/10W 1 参考号 部品号 部品名称 & 说明 件数 备注 143 R6837 ERJ6ENF4702 M 47KOHM, 1/10W 1 R6839 ERJ6GEYJ472 M 4.7KOHM,J,1/10W 1 R6841 ERJ12YJ153U M 15KOHM, 1/2W 1 R6842 ERJ14YJ433U M 43KOHM, 1/2W 1 R6843 ERJ6GEYJ623 M 62KOHM,J,1/10W 1 R6844 ERG2FJS101D M 100 OHM, J, 2W 1 R6845 ERJ6GEYJ623 M 62KOHM,J,1/10W 1 R6846,47 ERJ6GEYJ563 M 56KOHM,J,1/10W 2 R6848 ERJ6GEYJ103 M 10KOHM,J,1/10W 1 R6849,50 ERJ6ENF6802 M 68KOHM, 1/10W 2 R6851 ERJ6ENF4221 M4.22KOHM, 1/10W 1 R6852 ERJ6ENF2491 M2.49KOHM, 1/10W 1 R6853 ERJ6GEYJ101 M 100 OHM,J,1/10W 1 R6860 D0D28R2JA021 M 8.2 OHM,J,2W 1 R6861 ERJ6ENF3902 M 39KOHM, 1/10W 1 R6862,63 ERJ6ENF4702 M 47KOHM, 1/10W 2 R6864 ERJ6ENF9101 M 9.1KOHM, 1/10W 1 R6865,66 ERJ6ENF2201 M 2.2KOHM, 1/10W 2 R6867 ERJ6GEYJ392 M 3.9KOHM,J,1/10W 1 R6868 ERJ6GEYJ223 M 22KOHM,J,1/10W 1 R6869 ERJ6GEYJ472 M 4.7KOHM,J,1/10W 1 R6871-73 ERJ6ENF3902 M 39KOHM, 1/10W 3 R6874 ERJ6ENF8201 M 8.2KOHM, 1/10W 1 R6875 ERJ6ENF3301 M 3.3KOHM, 1/10W 1 R6876 ERJ6ENF1201 M 1.2KOHM, 1/10W 1 R6877 ERJ6GEYJ392 M 3.9KOHM,J,1/10W 1 R6878 ERJ6GEYJ223 M 22KOHM,J,1/10W 1 R6879 ERJ6GEYJ472 M 4.7KOHM,J,1/10W 1 R6886-88 ERJ6GEYJ224 M 220KOHM,J,1/10W 3 R6901 ERJ6GEYJ101 M 100 OHM,J,1/10W 1 R6902-04 ERJ3GEYJ220 M 22 OHM,J,1/16W 3 R6905 ERJ6GEYJ221 M 220 OHM,J,1/10W 1 R6909 ERJ6GEYJ221 M 220 OHM,J,1/10W 1 R6913 ERJ6GEYJ221 M 220 OHM,J,1/10W 1 R6917 ERJ6GEYJ221 M 220 OHM,J,1/10W 1 R6924 ERJ6GEYJ221 M 220 OHM,J,1/10W 1 R6931-34 ERJ6GEYJ103 M 10KOHM,J,1/10W 4 R6935,36 ERJ8GEYJ224 M 220KOHM, J,1/8W 2 R6951 ERJ6GEYJ101 M 100 OHM,J,1/10W 1 R6952-54 ERJ3GEYJ220 M 22 OHM,J,1/16W 3 R6955 ERJ6GEYJ221 M 220 OHM,J,1/10W 1 R6959 ERJ6GEYJ221 M 220 OHM,J,1/10W 1 R6963 ERJ6GEYJ221 M 220 OHM,J,1/10W 1 R6967 ERJ6GEYJ221 M 220 OHM,J,1/10W 1 R6971 ERJ6GEYJ221 M 220 OHM,J,1/10W 1 R6981-84 ERJ6GEYJ103 M 10KOHM,J,1/10W 4 R6985,86 ERJ8GEYJ224 M 220KOHM, J,1/8W 2 R7102 ERJ3GEYJ470 M 47 OHM,J,1/16W 1 R7103-06 D0GZ6R8JA020 M 6.8 OHM,J, 0.5W 4 R7108 ERJ3GEYJ470 M 47 OHM,J,1/16W 1 R7110 D0GZ6R8JA020 M 6.8 OHM,J, 0.5W 1 R7111 ERJ3GEYJ470 M 47 OHM,J,1/16W 1 R7112-15 D0GZ6R8JA020 M 6.8 OHM,J, 0.5W 4 R7116 ERJ3GEYJ470 M 47 OHM,J,1/16W 1 R7117 D0GZ6R8JA020 M 6.8 OHM,J, 0.5W 1 R7118 EXB38V102J 电阻阵列 1 R7119-22 D0GZ6R8JA020 M 6.8 OHM,J, 0.5W 4 R7124 D0GZ6R8JA020 M 6.8 OHM,J, 0.5W 1 R7125 ERJ3GEYJ470 M 47 OHM,J,1/16W 1 R7126 D0GZ6R8JA020 M 6.8 OHM,J, 0.5W 1 R7128 ERJ3GEYJ470 M 47 OHM,J,1/16W 1 R7129-31 D0GZ6R8JA020 M 6.8 OHM,J, 0.5W 3 R7132 EXB38V102J 电阻阵列 1 R7133 D0GZ6R8JA020 M 6.8 OHM,J, 0.5W 1 R7134 EXB38V102J 电阻阵列 1 R7136 EXB38V102J 电阻阵列 1 R7137 ERJ3GEYJ470 M 47 OHM,J,1/16W 1 R7138 EXB38V102J 电阻阵列 1 R7140 EXB38V102J 电阻阵列 1 R7141 ERJ3GEYJ470 M 47 OHM,J,1/16W 1 R7142 EXB38V102J 电阻阵列 1 R7143 ERJ3GEYJ220 M 22 OHM,J,1/16W 1 R7144,45 ERJ3GEYJ470 M 47 OHM,J,1/16W 2 R7148-50 ERJ3GEYJ220 M 22 OHM,J,1/16W 3 R7151-56 EXB38V470J 电阻阵列 6 R7157 ERJ3GEYJ470 M 47 OHM,J,1/16W 1 R7158-61 D0GZ6R8JA020 M 6.8 OHM,J, 0.5W 4 参考号 部品号 部品名称 & 说明 件数 备注 R7162 ERJ3GEYJ470 M 47 OHM,J,1/16W 1 R7167-70 EXB38V102J 电阻阵列 4 R7171-74 EXB38V470J 电阻阵列 4 R7175,76 EXB38V102J 电阻阵列 2 R7177,78 EXB38V470J 电阻阵列 2 R7179 EXB38V102J 电阻阵列 1 R7180,81 EXB38V470J 电阻阵列 2 R7182-86 ERJ3GEYJ220 M 22 OHM,J,1/16W 5 R7187 ERJ6GEYJ104 M 100KOHM,J,1/10W 1 R7188 ERJ6GEYJ223 M 22KOHM,J,1/10W 1 R7189 D0GD472JA059 M 4.7KOHM,J,0.25W 1 R7190,91 ERJ3GEY0R00 M 0 OHM, 1/16W 2 R7201,02 EXB38V102J 电阻阵列 2 R7203,04 EXB38V470J 电阻阵列 2 R7205,06 EXB38V102J 电阻阵列 2 R7208,09 EXB38V470J 电阻阵列 2 R7210,11 EXB38V102J 电阻阵列 2 R7212,13 EXB38V470J 电阻阵列 2 R7215,16 EXB38V102J 电阻阵列 2 R7217,18 EXB38V470J 电阻阵列 2 R7219 EXB38V102J 电阻阵列 1 R7220,21 EXB38V470J 电阻阵列 2 R7222 EXB38V102J 电阻阵列 1 R7223 ERJ3GEYJ470 M 47 OHM,J,1/16W 1 R7224-29 ERJ3GEYJ220 M 22 OHM,J,1/16W 6 R7230-33 D0GZ6R8JA020 M 6.8 OHM,J, 0.5W 4 R7235 ERJ3GEYJ470 M 47 OHM,J,1/16W 1 R7237 ERJ3GEYJ470 M 47 OHM,J,1/16W 1 R7238-41 D0GZ6R8JA020 M 6.8 OHM,J, 0.5W 4 R7243 ERJ3GEYJ470 M 47 OHM,J,1/16W 1 R7245 ERJ3GEYJ470 M 47 OHM,J,1/16W 1 R7246-49 D0GZ6R8JA020 M 6.8 OHM,J, 0.5W 4 R7251 ERJ3GEYJ470 M 47 OHM,J,1/16W 1 R7253 ERJ3GEYJ470 M 47 OHM,J,1/16W 1 R7254-57 D0GZ6R8JA020 M 6.8 OHM,J, 0.5W 4 R7259 ERJ3GEYJ470 M 47 OHM,J,1/16W 1 R7261 ERJ3GEYJ470 M 47 OHM,J,1/16W 1 R7262 ERJ6GEYJ223 M 22KOHM,J,1/10W 1 R7263 ERJ6GEYJ104 M 100KOHM,J,1/10W 1 R7264 ERJ3GEYJ470 M 47 OHM,J,1/16W 1 R7265-68 D0GZ6R8JA020 M 6.8 OHM,J, 0.5W 4 R7269 ERJ3GEYJ470 M 47 OHM,J,1/16W 1 R7272 D0GD472JA059 M 4.7KOHM,J,0.25W 1 R7273,74 ERJ3GEY0R00 M 0 OHM, 1/16W 2 R7275 ERJ6GEYJ224 M 220KOHM,J,1/10W 1 R9060-67 ERJ3GEYJ101 M 100 OHM,J,1/16W 8 R9070 ERJ3GEYJ470 M 47 OHM,J,1/16W 1 R9074 ERJ3GEYJ101 M 100 OHM,J,1/16W 1 R9076 ERJ3GEYJ101 M 100 OHM,J,1/16W 1 R9095,96 ERJ3GEYJ103 M 10KOHM,J,1/16W 2 R9099 ERJ3GEYJ101 M 100 OHM,J,1/16W 1 R9100,01 ERJ3GEYJ103 M 10KOHM,J,1/16W 2 R9102 ERJ3GEYJ101 M 100 OHM,J,1/16W 1 R9106 ERJ3GEYJ103 M 10KOHM,J,1/16W 1 R9107 ERJ3GEYJ332 M 3.3KOHM,J,1/16W 1 R9108,09 ERJ3GEYJ103 M 10KOHM,J,1/16W 2 R9110 ERJ3GEYJ101 M 100 OHM,J,1/16W 1 R9111 ERJ3GEYJ223 M 22KOHM,J,1/16W 1 R9113 ERJ3GEYJ100 M 10 OHM,J,1/16W 1 R9120 ERJ3GEYJ101 M 100 OHM,J,1/16W 1 R9121 ERJ3GEYJ104 M 100KOHM,J,1/16W 1 R9127 ERJ3GEYJ103 M 10KOHM,J,1/16W 1 R9129 ERJ3GEYJ683 M 68KOHM,J,1/16W 1 R9134 ERJ3GEYJ333 M 33KOHM,J,1/16W 1 R9140 ERJ6GEY0R00 M 0 OHM, 1/10W 1 R9141-45 ERJ3GEYJ101 M 100 OHM,J,1/16W 5 R9148 ERJ3GEYJ103 M 10KOHM,J,1/16W 1 R9149 ERJ3GEYJ472 M 4.7KOHM,J,1/16W 1 R9150,51 ERJ3GEYJ220 M 22 OHM,J,1/16W 2 R9152,53 ERJ3GEYJ472 M 4.7KOHM,J,1/16W 2 R9154,55 ERJ3GEYJ562 M 5.6KOHM,J,1/16W 2 R9156-59 ERJ3GEYJ103 M 10KOHM,J,1/16W 4 R9160,61 ERJ3GEY0R00 M 0 OHM, 1/16W 2 R9164-66 ERJ3GEYJ103 M 10KOHM,J,1/16W 3 R9167,68 ERJ3GEYJ101 M 100 OHM,J,1/16W 2 R9169 ERJ3GEYJ103 M 10KOHM,J,1/16W 1 R9170-72 ERJ3GEYJ393 M 39KOHM,J,1/16W 3 参考号 部品号 部品名称 & 说明 件数 备注 144 R9173-75 ERJ3GEYJ103 M 10KOHM,J,1/16W 3 R9177 ERJ3GEYJ223 M 22KOHM,J,1/16W 1 R9178 ERJ3GEYJ103 M 10KOHM,J,1/16W 1 R9180 ERJ3GEYJ103 M 10KOHM,J,1/16W 1 R9181-84 ERJ3GEYJ102 M 1KOHM,J,1/16W 4 R9185,86 ERJ3GEYJ220 M 22 OHM,J,1/16W 2 R9187,88 ERJ3GEYJ562 M 5.6KOHM,J,1/16W 2 R9189,90 ERJ3GEYJ103 M 10KOHM,J,1/16W 2 R9192 ERJ3GEY0R00 M 0 OHM, 1/16W 1 R9193 ERJ3GEYJ103 M 10KOHM,J,1/16W 1 R9194 ERJ3GEY0R00 M 0 OHM, 1/16W 1 R9196 ERJ3GEYJ103 M 10KOHM,J,1/16W 1 R9198 ERJ3GEYJ472 M 4.7KOHM,J,1/16W 1 R9199 ERJ3GEYJ272 M 2.7KOHM,J,1/16W 1 R9201,02 ERJ3GEYJ472 M 4.7KOHM,J,1/16W 2 R9203 ERJ3GEYJ102 M 1KOHM,J,1/16W 1 R9204,05 ERJ3GEYJ472 M 4.7KOHM,J,1/16W 2 R9206,07 ERJ3GEYJ102 M 1KOHM,J,1/16W 2 R9209 ERJ3GEYJ100 M 10 OHM,J,1/16W 1 R9210 ERJ3GEYJ272 M 2.7KOHM,J,1/16W 1 R9215 ERJ3GEYJ123 M 12KOHM,J,1/16W 1 R9217-22 ERJ3GEYJ103 M 10KOHM,J,1/16W 6 R9236 ERJ3GEY0R00 M 0 OHM, 1/16W 1 R9237 ERJ3GEYJ103 M 10KOHM,J,1/16W 1 R9244,45 ERJ3GEYJ101 M 100 OHM,J,1/16W 2 R9247,48 ERJ3GEYJ472 M 4.7KOHM,J,1/16W 2 R9367 ERJ3GEYJ181 M 180 OHM,J,1/16W 1 R9371 EXB2HV470JV 电阻阵列 1 R9372 ERJ3GEYJ470 M 47 OHM,J,1/16W 1 R9373 ERJ3GEYJ330 M 33 OHM,J,1/16W 1 R9374 EXB38V470J 电阻阵列 1 R9375 ERJ3GEYJ151 M 150 OHM,J,1/16W 1 R9389,90 ERJ3GEYJ272 M 2.7KOHM,J,1/16W 2 R9391 ERJ3GEYJ103 M 10KOHM,J,1/16W 1 R9404 EXB2HV470JV 电阻阵列 1 R9412-21 EXB38V470J 电阻阵列 10 R9428 EXB38V103J 电阻阵列 1 R9430 ERJ3GEYJ103 M 10KOHM,J,1/16W 1 R9433 ERJ3GEYJ272 M 2.7KOHM,J,1/16W 1 R9437 ERJ3GEYJ272 M 2.7KOHM,J,1/16W 1 R9438 ERJ3GEYJ103 M 10KOHM,J,1/16W 1 R9440 EXB2HV470JV 电阻阵列 1 R9441 ERJ3GEYJ472 M 4.7KOHM,J,1/16W 1 R9442 ERJ3GEYJ103 M 10KOHM,J,1/16W 1 R9443 ERJ3GEYJ104 M 100KOHM,J,1/16W 1 R9444 EXB2HV470JV 排阻 1 R9445 ERJ3GEYJ220 M 22 OHM,J,1/16W 1 R9446 EXB2HV470JV 电阻阵列 1 R9448 ERJ3GEYJ220 M 22 OHM,J,1/16W 1 R9449,50 EXB2HV470JV 排阻 2 R9451,52 ERJ3GEYJ220 M 22 OHM,J,1/16W 2 R9453-57 EXB2HV470JV 排阻 5 R9458,59 ERJ3GEYJ470V M 82 OHM,J,1/16W 2 R9460,61 ERJ3GEYJ220 M 22 OHM,J,1/16W 2 R9462,63 EXB38V470J 电阻阵列 2 R9464,65 ERJ3GEYJ220 M 22 OHM,J,1/16W 2 R9466,67 ERJ3GEYJ470V M 82 OHM,J,1/16W 2 R9468 ERJ3GEYJ101 M 100 OHM,J,1/16W 1 R9469 ERJ3GEYJ104 M 100KOHM,J,1/16W 1 R9470 ERJ3GEYJ472 M 4.7KOHM,J,1/16W 1 R9471 ERJ3GEYJ103 M 10KOHM,J,1/16W 1 R9472 ERJ3GEYJ104 M 100KOHM,J,1/16W 1 R9475 ERJ3GEYJ103 M 10KOHM,J,1/16W 1 R9480 ERJ3GEY0R00 M 0 OHM, 1/16W 1 R9482-85 ERJ3EKF1001 M 1KOHM, 1/16W 4 R9486 ERJ3GEYJ330 M 33 OHM,J,1/16W 1 R9487 ERJ3GEYJ151 M 150 OHM,J,1/16W 1 R9488 ERJ3GEYJ330 M 33 OHM,J,1/16W 1 R9489-95 ERJ3GEYJ470 M 47 OHM,J,1/16W 7 R9506 ERJ3GEYJ220 M 22 OHM,J,1/16W 1 R9507 ERJ3GEYJ560 M 56 OHM,J,1/16W 1 R9512 ERJ3GEY0R00 M 0 OHM, 1/16W 1 R9514 ERJ3GEY0R00 M 0 OHM, 1/16W 1 R9515 ERJ3GEYJ470 M 47 OHM,J,1/16W 1 R9523 ERJ3GEYJ103 M 10KOHM,J,1/16W 1 R9525 ERJ3GEYJ103 M 10KOHM,J,1/16W 1 R9526 ERJ3GEY0R00 M 0 OHM, 1/16W 1 参考号 部品号 部品名称 & 说明 件数 备注 R9527 EXB2HV272JV 电阻阵列 1 R9529,30 ERJ3GEYJ103 M 10KOHM,J,1/16W 2 R9531-33 ERJ3GEYJ470 M 47 OHM,J,1/16W 3 R9534 EXB38V470J 电阻阵列 1 R9535,36 ERJ3GEYJ470 M 47 OHM,J,1/16W 2 R9537 ERJ3GEYJ103 M 10KOHM,J,1/16W 1 R9539 ERJ3GEY0R00 M 0 OHM, 1/16W 1 R9542 ERJ3GEYJ680 M 68 OHM,J,1/16W 1 R9543,44 ERJ3GEYJ103 M 10KOHM,J,1/16W 2 R9545 ERJ3GEYJ304V M 300KOHM,J,1/16W 1 R9546 ERJ3GEYJ103 M 10KOHM,J,1/16W 1 R9548-50 ERJ3GEYJ103 M 10KOHM,J,1/16W 3 R9552-54 ERJ3GEYJ470 M 47 OHM,J,1/16W 3 R9556 ERJ3GEYJ103 M 10KOHM,J,1/16W 1 R9560 ERJ3GEYJ103 M 10KOHM,J,1/16W 1 R9574 ERJ3GEY0R00 M 0 OHM, 1/16W 1 R9578 ERJ3GEY0R00 M 0 OHM, 1/16W 1 R9580-83 ERJ3EKF1001 M 1KOHM, 1/16W 4 R9584 ERJ3GEYJ330 M 33 OHM,J,1/16W 1 R9585,86 ERJ3GEYJ470 M 47 OHM,J,1/16W 2 R9587-95 EXB38V470J 电阻阵列 9 R9596-99 ERJ3GEYJ470 M 47 OHM,J,1/16W 4 R9602 ERJ3GEY0R00 M 0 OHM, 1/16W 1 R9616 ERJ3GEY0R00 M 0 OHM, 1/16W 1 R9619,20 ERJ3GEYJ472 M 4.7KOHM,J,1/16W 2 R9622 ERJ3GEY0R00 M 0 OHM, 1/16W 1 R9625,26 ERJ3GEYJ103 M 10KOHM,J,1/16W 2 R9628 ERJ3GEYJ103 M 10KOHM,J,1/16W 1 R9630 ERJ3GEYJ103 M 10KOHM,J,1/16W 1 R9631 EXB2HV272JV 电阻阵列 1 R9632-34 ERJ3GEYJ470 M 47 OHM,J,1/16W 3 R9637 ERJ3GEYJ470 M 47 OHM,J,1/16W 1 R9639 ERJ3GEYJ470 M 47 OHM,J,1/16W 1 R9641 ERJ3GEYJ470 M 47 OHM,J,1/16W 1 R9643 ERJ3GEY0R00 M 0 OHM, 1/16W 1 R9645 ERJ3GEY0R00 M 0 OHM, 1/16W 1 R9800 ERJ3EKF1302 M 13KOHM, 1/16W 1 R9801 ERJ3EKF2402 M 24KOHM, 1/16W 1 R9802 ERJ3EKF6202 M 62KOHM, 1/16W 1 R9803 ERJ3GEY0R00 M 0 OHM, 1/16W 1 R9804 ERJ3EKF2402 M 24KOHM, 1/16W 1 R9805 ERJ3EKF3002 M 30KOHM, 1/16W 1 R9806 ERJ3EKF3902 M 39KOHM, 1/16W 1 R9807 ERJ3GEY0R00 M 0 OHM, 1/16W 1 R9808 ERJ3GEYJ104 M 100KOHM,J,1/16W 1 R9810 ERJ3EKF3001 M 3KOHM, 1/16W 1 R9813 ERJ3EKF2401 M 2.4KOHM, 1/16W 1 R9814 ERJ3EKF6802 M 68KOHM, 1/16W 1 R9815 ERJ3EKF2202 M 22KOHM, 1/16W 1 R9816 ERJ3EKF8202 M 82KOHM, 1/16W 1 R9821 ERJ3GEYJ103 M 10KOHM,J,1/16W 1 R9823-28 ERJ3GEYJ101 M 100 OHM,J,1/16W 6 R9830,31 ERJ3GEYJ103 M 10KOHM,J,1/16W 2 R9838,39 ERJ3GEYJ101 M 100 OHM,J,1/16W 2 R9840 ERJ3GEYJ220 M 22 OHM,J,1/16W 1 R9841 ERJ3GEY0R00 M 0 OHM, 1/16W 1 R9842-44 ERJ3GEYJ101 M 100 OHM,J,1/16W 3 R9845 ERJ3GEYJ562 M 5.6KOHM,J,1/16W 1 R9846,47 EXB2HV272JV 电阻阵列 2 R9848,49 EXB2HV470JV 电阻阵列 2 R9850 ERJ3GEYJ473 M 47KOHM,J,1/16W 1 R9854 ERJ3GEYJ101 M 100 OHM,J,1/16W 1 R9859 EXB38V101J 电阻阵列 1 R9868 ERJ3GEYJ104 M 100KOHM,J,1/16W 1 R9869-71 ERJ3GEYJ103 M 10KOHM,J,1/16W 3 R9872 ERJ3GEY0R00 M 0 OHM, 1/16W 1 R9875-77 ERJ3GEYJ103 M 10KOHM,J,1/16W 3 R9878 ERJ3EKF3902 M 39KOHM, 1/16W 1 R9879 ERJ3EKF2002 M 20KOHM, 1/16W 1 R9880 ERJ3EKF3602 M 36KOHM, 1/16W 1 R9883 ERJ3GEY0R00 M 0 OHM, 1/16W 1 R9884 ERJ3GEYJ104 M 100KOHM,J,1/16W 1 R9891 ERJ3EKF4702 M 47KOHM, 1/16W 1 R9892 ERJ3EKF1502 M 15KOHM, 1/16W 1 R9893 ERJ3EKF3602 M 36KOHM, 1/16W 1 R9896 ERJ3GEY0R00 M 0 OHM, 1/16W 1 R9897 ERJ3GEYJ104 M 100KOHM,J,1/16W 1 参考号 部品号 部品名称 & 说明 件数 备注 145 RM2501 PNA4701M05TV 遥控接收器 1 S1 K1KA03BA0061 3P 连接接头 1 SC2 K1KA02A00626 2P 连接接头 1 SC20 K1KA20AA0008 20P 连接接头 1 SC23 K1KA03AA0193 3P 连接接头 1 SC30 K1KA08AA0192 8P 连接接头 1 SC41,42 K1ML80B00001 80P 连接接头 2 SC45,46 K1KA09A00239 9P 连接接头 2 SCMM1 TMME260 线夹 1 SCMM3 TMME260 线夹 1 SD1-D4 K1MN96B00005 96P 连接接头 4 SD46 K1KB09A00045 9P 连接接头 1 SS12 K1KA10AA0194 10P 连接接头 1 SS23 K1KA12AA0194 12P 连接接头 1 SS34 K1KA03AA0193 3P 连接接头 1 SS41-44 K1MN13B00020 13P 连接接头 4 SU1-U4 K1MN96B00005 96P 连接接头 4 SU45 K1KB09A00045 9P 连接接头 1 SW2500 K0F162B00002 开关 1 SW3753-57 EVQ11G05R 开关 5 T6602 ETS25AZ139AD 转接变压器 1 TA5,A6 K1KB15B00013 15P 连接接头 2 TU001 ENG39A26GF 调谐器 1 VR6000 EVMEASA00B14 控制 10KOHMB 0.3W 1 VR6600 EVMEASA00B13 控制 1KOHMB 0.3W 1 VR6602 EVMEASA00B53 控制 5KOHMB 0.3W 1 X1100 H0J100500030 晶体 1 X1101 H0J327200114 晶体 1 X2101 H0J184500027 晶体 1 X4004 H0J270500087 晶体 1 X9000 H2D200500011 晶体 1 X9500 H0J200500038 晶体 1 ZA2101-08 TESA169 防护夹头 8 ZA2300,01 K4CZ01000027 与 ALCO K9 兼容 2 ZA3401-03 K4CZ01000027 与 ALCO K9 兼容 3 ZA3405 K4CZ01000027 与 ALCO K9 兼容 1 ZA3701 K4CD01000013 AV 端子 1 ZA4001,02 K4CD08000002 AV 端子 2 ZA6001,02 K4CD01000011 AV 端子 2 ZA6005 K4CD01000011 AV 端子 1 ZA6401-03 K4CD01000011 AV 端子 3 ZA7101-04 K4AD01Z00001 端子 4 ZA7201-04 K4AD01Z00001 端子 4 ZA9001 K4CD01000011 AV 端子 1 C402 F1J1C1050011 C 1UF, Z, 50V 1 C404 F0CAF105A021 C 1UF, 250V 1 C407 EEUEB2W220B E 22UF, 450V 1 C408 ECJ2XB1H102K C 1000PF, K, 50V 1 C409 F0CAF225A021 C 22UF, 250V 1 C410 ECJ2XB1H103K C 0.01UF, K, 50V 1 C413 ECJ2XB1H104K C 0.1UF, K, 50V 1 C414 ECQU2A473ML P 0.047UF, M,250V 1 C421 F1J1C1050011 C 1UF, Z, 50V 1 C422 ECJ2XB1H103K C 0.01UF, K, 50V 1 C423 ECJ2XB1H472K C 4700PF, K, 50V 1 C425 ECJ2XB1H103K C 0.01UF, K, 50V 1 C426 ECJ2XC1H471J C 470PF, J, 50V 1 C427 F1J1C1050011 C 1UF, Z, 50V 1 C428 ECJ2XC1H221J C 220PF, J, 50V 1 C429 F1E2J4730001 C 0.047PF, , 600V 1 C431 ECJ2XB1H102K C 1000PF, K, 50V 1 C432 F1J1C1050011 C 1UF, Z, 50V 1 参考号 部品号 部品名称 & 说明 件数 备注 C433 ECJ3XB1E104K C 0.1UF, K, 25V 1 C434 F1J1C1050011 C 1UF, Z, 50V 1 C436 F1J1C1050011 C 1UF, Z, 50V 1 C440 ECA1HM100 E 10UF, 50V 1 C443,44 F1A3A102A040 C 1000PF, J, 1KV 2 C445 F1J1C1050011 C 1UF, Z, 50V 1 C446 F2B2W3910005 C 390UF, 450V 1 C450 ECJ2XB1H103K C 0.01UF, K, 50V 1 C451 F1A3A101A040 C 100PF, J, 1KV 1 C457 ECWH12333RHV P 0.013UF,J,1.2KV 1 C460,61 F1A3A331A039 E 330UF, 1KV 2 C462 ECJ3YB1E105K C 1UF, K, 25V 1 C463 ECJ2XC1H220J C 22UF, J, 50V 1 C467 ECKCNA221KB7 C 220PF, M, 1 C468 ECJ2XB1H103K C 0.01UF, K, 50V 1 C469 ECKCNA221KB7 C 220PF, M, 1 C470 F0CAF105A021 C 1UF, 250V 1 C473,74 ECKCNA101KB7 C 100PF 2 C476 ECKCNA101KB7 C 100PF 1 C478 ECKCNA101KB7 C 100PF 1 C493 ECA1HM470 E 47UF, 50V 1 C494 F2A2E1R00008 E 1.0UF, 250V 1 C497 ECA1HM470 E 47UF, 50V 1 C501,02 ECJ2XB1H103K C 0.01UF, K, 50V 2 C503 ECJ2XC1H471J C 470PF, J, 50V 1 C504 F1J1C1050011 C 1UF, Z, 50V 1 C505 ECJ2XB1H102K C 1000PF, K, 50V 1 C506,07 ECJ2XB1H103K C 0.01UF, K, 50V 2 C508 ECJ2XC1H471J C 470PF, J, 50V 1 C509 ECA1EHG101 E 100UF, 25V 1 C510 ECJ2XB1H104K C 0.1UF, K, 50V 1 C511 ECJ2XB1H102K C 1000PF, K, 50V 1 C512-14 ECJ2XC1H471J C 470PF, J, 50V 3 C515 F2A1A1220011 E 1200UF, 10V 1 C516 ECJ2XB1C474K C 0.47UF, Z, 16V 1 C517 F2A1E221A096 E 220UF, 25V 1 C518 ECJ2XB1H104K C 0.1UF, K, 50V 1 C519 F1J1C1050011 C 1UF, Z, 50V 1 C523 ECJ3YB1E105K C 1UF, K, 25V 1 C526 ECJ2XB1H223K C 0.022UF, K, 50V 1 C527 ECJ3YB1E475K C 4.7UF, K, 25V 1 C528,29 F1J1C1050011 C 1UF, Z, 50V 2 C530 ECJ2VB1H333K C 0.033UF, K, 50V 1 C531 ECJ3YB1E105K C 1UF, K, 25V 1 C533 ECJ2XB1H103K C 0.01UF, K, 50V 1 C534 ECJ2XC1H471J C 470PF, J, 50V 1 C546,47 ECJ2XB1H102K C 1000PF, K, 50V 2 C550 ECJ2XC1H331J C 330PF, J, 50V 1 C551,52 ECJ2XB1H104K C 0.1UF, K, 50V 2 C554 F1J1C1050011 C 1UF, Z, 50V 1 C555 F2A2C4710003 E 1000UF, 160V 1 C556,57 EEUFC1E152 E 1500UF, 25V 2 C558 F2A1E4710065 E 470UF, 25V 1 C559 F2A1A1220011 E 1200UF, 10V 1 C562 ECJ2XB1H223K C 0.022UF, K, 50V 1 C571 ECJ2XC1H330J C 33PF, J, 50V 1 C574 ECJ2XB1H104K C 0.1UF, K, 50V 1 C577 F2A2A330A022 E 33UF, 100V 1 C581 ECJ2XB1H223K C 0.022UF, K, 50V 1 C583 ECJ2XB1H102K C 1000PF, K, 50V 1 C584,85 ECJ2XB1H223K C 0.022UF, K, 50V 2 C587 ECJ2XB1H332K C 3300PF, K, 50V 1 C601 ECJ2XB1H103K C 0.01UF, K, 50V 1 C603 ECJ2FB1E105K C 1UF, K, 25V 1 C604,05 F2A2D1510008 E 150UF, 200V 2 C607 F1J1C1050011 C 1UF, Z, 50V 1 C608 ECJ2XB1H103K C 0.01UF, K, 50V 1 C610 F1J1C1050011 C 1UF, Z, 50V 1 C611 F2B2D1720005 E 1700UF,　 200V 1 C612,13 ECJ2XB1H103K C 0.01UF, K, 50V 2 C615 F2B2D1720005 E 1700UF,　 200V 1 C616 F1A3A102A040 C 1000PF, J, 1KV 1 C619 ECJ2XB1H104K C 0.1UF, K, 50V 1 C620 ECJ2XB1H103K C 0.01UF, K, 50V 1 C623 ECA1HM100 E 10UF, 50V 1 C624 ECJ2XB1H103K C 0.01UF, K, 50V 1 参考号 部品号 部品名称 & 说明 件数 备注 146 C625 ECA1HM100 E 10UF, 50V 1 C626 ECJ2XB1H103K C 0.01UF, K, 50V 1 C627 ECJ2XB1H102K C 1000PF, K, 50V 1 C629-31 ECJ2XB1H103K C 0.01UF, K, 50V 3 C632 ECJ2XC1H331J C 330PF, J, 50V 1 C634 ECJ2XB1H102K C 1000PF, K, 50V 1 C635 ECJ2XB1H103K C 0.01UF, K, 50V 1 C638,39 ECJ2XB1H103K C 0.01UF, K, 50V 2 C640 ECJ2XB1H104K C 0.1UF, K, 50V 1 C641 ECJ2XB1H102K C 1000PF, K, 50V 1 C643 ECA1HM470 E 47UF, 50V 1 C650 ECJ2XB1H104K C 0.1UF, K, 50V 1 C653 ECJ2XB1H102K C 1000PF, K, 50V 1 C654 ECJ3YB1E105K C 1UF, K, 25V 1 C655,56 ECJ3YB1E225K C 2.2UF, K, 25V 2 C657 ECJ2XB1H102K C 1000PF, K, 50V 1 C658 ECJ3YB1E105K C 1UF, K, 25V 1 C659 ECJ2XB1H103K C 0.01UF, K, 50V 1 C660 ECJ2FB1C225K C 22UF, K, 16V 1 C661,62 ECJ2XB1H103K C 0.01UF, K, 50V 2 D401 B0FBAT000006 二极管 1 D404 B0EBKT000007 二极管 1 D407 MA111 二极管 1 D411 B0BB17000009 二极管 1 D412 B0HAMM000122 二极管 1 D415 B0JAME000099 二极管 1 D416 B0HAMP000067 二极管 1 D417 B0HAPR000013 二极管 1 D418 B0BC8R100013 二极管 1 D419,20 B0HAPR000013 二极管 2 D423 MA188 二极管 1 D425 MA188 二极管 1 D429 ERA15-10 二极管 1 D430 MA111 二极管 1 D431,32 B0JCDD000002 二极管 2 D433 B0BC01400033 二极管 1 D435 ERA15-10 二极管 1 D436-38 MA4200M 稳压二极管 3 D441 B0HAMM000122 二极管 1 D444 B0HAMM000122 二极管 1 D445 MA4360H 稳压二极管 1 D501 B0HAPR000012 二极管 1 D503,04 MA165 二极管 2 D505 B0JAME000099 二极管 1 D506 MAZ80470LL 稳压二极管 1 D507,08 B0BC7R400023 二极管 2 D509 B0JANG000018 二极管 1 D511 B0JAML000011 二极管 1 D512,13 MA111 二极管 2 D514 B0BC6R100025 二极管 1 D515 B0BC3R200008 二极管 1 D516-18 MA4330M 稳压二极管 3 D520 MA111 二极管 1 D521 B0JAME000099 二极管 1 D528,29 MA153 二极管 2 D530 B0BC9R900013 二极管 1 D531 B0HBSN000013 二极管 1 D535 MA188 二极管 1 D536 B0JBSG000026 二极管 1 D538 B0BC5R100039 二极管 1 D539,40 B0AARR000010 二极管 2 D542 MA4200M 稳压二极管 1 D543 B0BC01400033 二极管 1 D544,45 MA4200M 稳压二极管 2 D549 B0BC02500008 二极管 1 D551 B0BC01300033 二极管 1 D555 B0BC7R400023 二极管 1 D559 B0BC7R400023 二极管 1 D563 B0BC6R100025 二极管 1 D569-72 B0BC02500008 二极管 4 D574 MA165 二极管 1 D575 MA188 二极管 1 D579 MA165 二极管 1 D582 MAZ705600F 稳压二极管 1 D585 B0BC7R400023 二极管 1 D586 B0HAMP000067 二极管 1 参考号 部品号 部品名称 & 说明 件数 备注 D587 MA188 二极管 1 D588 B0BC3R200008 二极管 1 D590 B0BC3R200008 二极管 1 D596 ERA15-10 二极管 1 D598 B0BC5R100039 二极管 1 D599 B0JCND000009 二极管 1 D600 B0BC7R400023 二极管 1 D601 B0BC5R100039 二极管 1 D602 B0BC8R100013 二极管 1 F410 K5G102B00020 保险丝 1 IC401 CNC1S171R IC 1 IC402 C0DAEMB00004 IC 1 IC403-05 CNC1S171R IC 3 IC406 C0DAZZZ00021 IC 1 IC408 CNC1S171R IC 1 IC409 MIP2G40MPSCF IC 1 IC410 CNC1S171R IC 1 IC411 C0DAEMB00004 IC 1 IC412 CNC1S171R IC 1 IC501 C2ABDB000110 IC 1 IC502 C0EBH0000210 IC 1 IC504 C0DAEMB00004 IC 1 IC505 CNC1S171R IC 1 IC506 C0ZBZ0000878 IC 1 IC507 CNC1S171R IC 1 IC509 C0DABZZ00010 IC 1 IC510 C0DBAZG00034 IC 1 IC512 C0DAEMB00004 IC 1 IC520 LSSK0062 IC 1 L403 EXCELSA35 头扼流圈 1 L404,05 G0B123K00004 扼流线圈 2 L410 ELF17N004A LINE 滤波器 1 L510 EXCELDR25C 头扼流圈 1 L511 G0A470ZA0033 扼流线圈 1 L512 ELESE4R7JA 校正线圈 1 L513 EXCELDR25C 头扼流圈 1 P2 K1KA02A00626 2P 连接接头 1 P5 K1KA11AA0194 11P 连接接头 1 P9 K1KA03A00537 3P 连接接头 1 P10 K1KA06A00452 6P 连接接头 1 P11 K1KA02A00626 2P 连接接头 1 P12 K1KA10AA0194 10P 连接接头 1 P23 K1KA03AA0193 3P 连接接头 1 P25 K1KA20AA0178 20P 连接接头 1 PMM1 TMM7464-2 线夹 1 PMM2,M3 TMME088 线夹 2 PMM4-M6 TMM7464-2 线夹 3 PMM7 TMME047 线夹 1 PR401 K5Y502BA0001 保险丝 1 PR505 K5H5022A0023 保险丝 1 PR509 ERBSE0R50U 保险丝 1 PR601 K5G312B00012 保险丝 1 Q401 B1CHND000004 三极管 1 Q402 B1DFDD000019 三极管 1 Q404 B1BCCF000022 三极管 1 Q406 B1DEHQ000007 三极管 1 Q407 B1HFCFA00021 三极管 1 Q408,09 B1DHCD000034 三极管 2 Q412,13 B1DEGQ000070 三极管 2 Q418 2SD1819A 三极管 1 Q420-22 2SD1819A 三极管 3 Q434 B1CEJQ000003 三极管 1 Q501,02 2SD1820A 三极管 2 Q505 B1CEJQ000002 三极管 1 Q507 B1DAGQ000013 三极管 1 Q508 B1HBCFA00033 三极管 1 Q509 B1HDCEA00001 三极管 1 Q510 B1DHBD000005 三极管 1 Q512 B1CBGD000001 FET 1 参考号 部品号 部品名称 & 说明 件数 备注 147 Q517 B1HBCFA00033 三极管 1 Q520 B1HBCFA00033 三极管 1 Q521 B1CBGD000001 FET 1 Q524 B1CFGF000008 三极管 1 Q525 B1CBGD000001 FET 1 Q527 B1CERL000005 三极管 1 Q530 2SD1819A 三极管 1 Q535 2SD1819A 三极管 1 Q537 B1DFDD000019 三极管 1 Q538 B1CBGD000001 FET 1 Q540 B1DHCD000034 三极管 1 Q541 B1CBGD000001 FET 1 Q551 B1CBGD000001 FET 1 Q553 2SD1819A 三极管 1 Q554 B1DHCD000034 三极管 1 Q555,56 B1DFGD000045 三极管 2 Q557-59 2SD1819A 三极管 3 Q561 2SD1819A 三极管 1 Q563 B1CFGF000008 三极管 1 Q564,65 2SB1218ARL 三极管 2 Q566 2SD1819A 三极管 1 Q568 B1CHGD000006 三极管 1 Q569 B1CBGD000001 FET 1 R401 ERJ6GEYJ103 M 10KOHM,J,1/10W 1 R402 ERJ6GEYJ821 M 820 OHM,J,1/10W 1 R403 ERJ6GEYJ105 M 1MOHM,J,1/10W 1 R404 ERJ6GEYJ102 M 1KOHM,J,1/10W 1 R406 ERX12SJ2R2V M 2.2 OHM, J,1/2W 1 R407 ERJ8ENF4303 M 43KOHM, 1/8W 1 R410 D1F5100E0003 片状电阻 1 R412 ERJ6GEY0R00 M 0 OHM, 1/10W 1 R413 D1F5100E0003 片状电阻 1 R414 ERJ8GEYJ153 M 15KOHM, J,1/8W 1 R415 ERJ6GEYJ103 M 10KOHM,J,1/10W 1 R416 ERJ6GEYJ305 M 3MOHM,J,1/10W 1 R417 ERJ6ENF4303 M 430KOHM, 1/10W 1 R418 ERJ6GEYJ220 M 22 OHM,J,1/10W 1 R419 ERJ6GEYJ104 M 100KOHM,J,1/10W 1 R420 ERJ6GEY0R00 M 0 OHM, 1/10W 1 R421 ERJ6GEYJ333 M 33KOHM,J,1/10W 1 R422 ERJ6GEYJ334 M 330KOHM,J,1/10W 1 R423 ERJ6GEYJ102 M 1KOHM,J,1/10W 1 R424 ERJ6GEYJ223 M 22KOHM,J,1/10W 1 R425 ERJ6ENF3302 M 39KOHM, 1/10W 1 R426 ERJ6GEYJ103 M 10KOHM,J,1/10W 1 R427 ERJ8ENF4303 M 43KOHM, 1/8W 1 R428 ERJ6GEYJ103 M 10KOHM,J,1/10W 1 R429 ERJ6GEYJ4R7 M 4.7 OHM,J,1/10W 1 R430 ERJ6ENF4303 M 430KOHM, 1/10W 1 R431 ERJ6GEYJ103 M 10KOHM,J,1/10W 1 R432 ERJ6GEYJ102 M 1KOHM,J,1/10W 1 R433 ERJ6ENF1202 M 12KOHM, 1/10W 1 R434 ERJ8GEY0R00 M 0 OHM, 1/8W 1 R435 ERJ8ENF4303 M 43KOHM, 1/8W 1 R436 ERJ8GEYJ153 M 15KOHM, J,1/8W 1 R437 ERJ6GEYJ183 M 18KOHM,J,1/10W 1 R438 ERJ6GEYJ331 M 330 OHM,J,1/10W 1 R439 ERG12SJ120 M 12 OHM, J,1/2W 1 R440 ERJ8GEYJ474 M 470KOHM, J,1/8W 1 R441,42 ERJ6EKF6803 M 680KOHM, 1/10W 2 R443 EVMAASA00B23 控制 2KOHMB 1 R444 ERJ6GEYJ123 M 12KOHM,J,1/10W 1 R448,49 D0XGR10J0003 M 0.1OHM,J, 5W 2 R450 ERJ6GEYJ102 M 1KOHM,J,1/10W 1 R451 ERJ6GEYJ333 M 33KOHM,J,1/10W 1 R452 ERJ6GEYJ103 M 10KOHM,J,1/10W 1 R453 ERJ6GEYJ305 M 3MOHM,J,1/10W 1 R454 ERJ6GEYJ103 M 10KOHM,J,1/10W 1 R455 ERJ6GEYJ123 M 12KOHM,J,1/10W 1 R456 ERJ6GEYJ333 M 33KOHM,J,1/10W 1 R458 ERJ6GEYJ472 M 4.7KOHM,J,1/10W 1 R459 ERJ6ENF5102 M 680KOHM, 1/10W 1 R461 ERJ6GEYJ103 M 10KOHM,J,1/10W 1 R462 ERJ6ENF4303 M 430KOHM, 1/10W 1 R463 ERJ6GEYJ333 M 33KOHM,J,1/10W 1 R464 ERJ6ENF3302 M 33KOHM, 1/10W 1 参考号 部品号 部品名称 & 说明 件数 备注 R465 ERJ6ENF5603 M 560KOHM, 1/10W 1 R467 ERJ6GEYJ102 M 1KOHM,J,1/10W 1 R471 ERJ8GEYJ332 M 3.3KOHM, J,1/8W 1 R472,73 ERJ6ENF5603 M 560KOHM, 1/10W 2 R475 ERJ6EKF6803 M 680KOHM, 1/10W 1 R476,77 ERJ14YJ181U M 181 OHM, J,1/4W 2 R478 ERJ8GEYJ220 M 22 OHM, J,1/8W 1 R480 ERJ6ENF4702 M 47KOHM, 1/10W 1 R482 ERJ8GEYJ220 M 22 OHM, J,1/8W 1 R483 D0BF225JA030 M 22MOHM,J,0.05W 1 R487 ERJ6GEYJ472 M 4.7KOHM,J,1/10W 1 R488 ERJ6GEYJ104 M 100KOHM,J,1/10W 1 R490,91 ERJ6GEYJ473 M 47KOHM,J,1/10W 2 R492 ERJ6GEY0R00 M 0 OHM, 1/10W 1 R493 ERG12SJ120 M 12 OHM, J,1/2W 1 R494-96 ERJ6ENF5603 M 560KOHM, 1/10W 3 R497 ERJ6ENF1202 M 12KOHM, 1/10W 1 R498 ERG3SJ101 M 100 OHM, J, 3W 1 R499 D0BF394JA029 M 390KOHM,J,0.05W 1 R501 ERJ6GEYJ223 M 22KOHM,J,1/10W 1 R502,03 ERJ6GEYJ104 M 100KOHM,J,1/10W 2 R504 ERJ6GEYJ102 M 1KOHM,J,1/10W 1 R505 ERJ8GEYJ330 M 33 OHM, J,1/8W 1 R506 ERJ6GEYJ102 M 1KOHM,J,1/10W 1 R507 ERJ6GEYJ221 M 220 OHM,J,1/10W 1 R508 ERJ6GEYJ102 M 1KOHM,J,1/10W 1 R509-11 ERJ6GEYJ104 M 100KOHM,J,1/10W 3 R512 ERJ6GEYJ223 M 22KOHM,J,1/10W 1 R513,14 ERJ6GEYJ104 M 100KOHM,J,1/10W 2 R515,16 ERJ6GEYJ102 M 1KOHM,J,1/10W 2 R517 ERJ6GEYJ103 M 10KOHM,J,1/10W 1 R518 ERJ6GEYJ102 M 1KOHM,J,1/10W 1 R519,20 ERJ6GEYJ104 M 100KOHM,J,1/10W 2 R521,22 ERJ8GEYJ100 M 10 OHM, J,1/8W 2 R523 ERJ6GEYJ473 M 47KOHM,J,1/10W 1 R524 ERJ6GEYJ102 M 1KOHM,J,1/10W 1 R525 ERJ6GEYJ473 M 47KOHM,J,1/10W 1 R526,27 ERJ8GEYJ224 M 220KOHM, J,1/8W 2 R528 ERJ6GEYJ4R7 M 4.7 OHM,J,1/10W 1 R529 ERJ6GEYJ101 M 100 OHM,J,1/10W 1 R530 ERJ6RBD3302 M 33KOHM,F,1/10W 1 R532 ERJ6GEYJ102 M 1KOHM,J,1/10W 1 R533 ERJ6GEYJ163 M 16KOHM,J,1/10W 1 R534 ERJ6GEYJ473 M 47KOHM,J,1/10W 1 R535,36 ERJ6GEYJ102 M 1KOHM,J,1/10W 2 R537 ERJ6ENF1003 M 100KOHM, 1/10W 1 R538 ERJ6GEYJ104 M 100KOHM,J,1/10W 1 R539 ERJ6GEYJ103 M 10KOHM,J,1/10W 1 R540,41 ERJ6GEYJ105 M 1MOHM,J,1/10W 2 R542 ERJ6GEYJ102 M 1KOHM,J,1/10W 1 R543 ERJ6GEYJ153 M 15KOHM,J,1/10W 1 R544 ERJ6GEYJ331 M 330 OHM,J,1/10W 1 R545 ERJ6GEYJ103 M 10KOHM,J,1/10W 1 R546 ERJ6GEYJ102 M 1KOHM,J,1/10W 1 R547 ERJ6GEYJ101 M 100 OHM,J,1/10W 1 R548 ERJ6GEYJ102 M 1KOHM,J,1/10W 1 R549 ERJ6GEYJ103 M 10KOHM,J,1/10W 1 R550 ERJ6GEYJ473 M 47KOHM,J,1/10W 1 R551 ERJ6GEYJ334 M 330KOHM,J,1/10W 1 R552 ERJ6GEYJ103 M 10KOHM,J,1/10W 1 R553 ERJ6GEYJ101 M 100 OHM,J,1/10W 1 R554 ERJ6GEYJ102 M 1KOHM,J,1/10W 1 R555,56 ERJ6GEYJ105 M 1MOHM,J,1/10W 2 R557 ERJ6GEYJ104 M 100KOHM,J,1/10W 1 R558 ERJ6GEYJ474 M 470KOHM,J,1/10W 1 R559 ERJ6ENF8201 M 8.2KOHM, 1/10W 1 R560 ERJ6ENF9101 M 9.1KOHM, 1/10W 1 R561 ERJ6ENF5101 M 5.1KOHM, 1/10W 1 R562 ERJ6ENF4701 M 4.7KOHM, 1/10W 1 R563 ERJ6GEYJ2R2 M 2.2 OHM,J,1/10W 1 R564 ERJ6GEYJ104 M 100KOHM,J,1/10W 1 R565,66 ERJ6GEYJ105 M 1MOHM,J,1/10W 2 R567,68 ERJ8ENF1004 M 100KOHM, 1/8W 2 R569 ERJ6ENF3302 M 33KOHM, 1/10W 1 R570 ERJ6GEYJ104 M 100KOHM,J,1/10W 1 R571 ERJ6GEYJ105 M 1MOHM,J,1/10W 1 R572,73 ERJ8ENF3900 M 390 OHM, 1/8W 2 参考号 部品号 部品名称 & 说明 件数 备注 148 FLE20060600007 R574 ERJ6GEYJ331 M 330 OHM,J,1/10W 1 R575 ERJ6GEYJ102 M 1KOHM,J,1/10W 1 R576 ERJ6ENF1202 M 12KOHM, 1/10W 1 R577,78 ERJ6GEYJ473 M 47KOHM,J,1/10W 2 R579 ERJ6GEYJ103 M 10KOHM,J,1/10W 1 R580,81 ERJ6GEYJ473 M 47KOHM,J,1/10W 2 R582 ERJ6ENF1002 M 10KOHM, 1/10W 1 R583 ERJ6GEYJ473 M 47KOHM,J,1/10W 1 R584 ERJ6GEYJ103 M 10KOHM,J,1/10W 1 R585 ERJ6GEYJ333 M 33KOHM,J,1/10W 1 R586 ERJ6GEYJ473 M 47KOHM,J,1/10W 1 R587 ERJ8RQJR22V M0.22 OHM, 1/8W 1 R588 ERJ8ENF3900 M 390 OHM, 1/8W 1 R589,90 ERJ8GEYJ123 M 12KOHM, J,1/8W 2 R591 ERJ6GEYJ105 M 1MOHM,J,1/10W 1 R592 ERJ6ENF3001 M 3KOHM, 1/10W 1 R593 ERJ6ENF5601 M 5.6KOHM, 1/10W 1 R594 ERJ6GEYJ151 M 150 OHM,J,1/10W 1 R595 ERJ8GEYJ222 M 2.2KOHM, J,1/8W 1 R596 ERJ6GEYJ101 M 100 OHM,J,1/10W 1 R597,98 ERJ6ENF3302 M 33KOHM, 1/10W 2 R599,00 ERJ8ENF3900 M 390 OHM, 1/8W 2 R601 ERJ6GEYJ473 M 47KOHM,J,1/10W 1 R602 ERJ6ENF3301 M 3.3KOHM, 1/10W 1 R603 ERJ6GEYJ333 M 33KOHM,J,1/10W 1 R606 ERJ6ENF1201 M 1.2KOHM, 1/10W 1 R607 ERJ6ENF2202 M 2.2KOHM, 1/10W 1 R608 ERJ8GEYJ332 M 3.3KOHM, J,1/8W 1 R609 ERJ6GEYJ102 M 1KOHM,J,1/10W 1 R610,11 ERJ6GEYJ473 M 47KOHM,J,1/10W 2 R612 ERJ6GEYJ222 M 2.2KOHM,J,1/10W 1 R613 ERJ6ENF2402 M 24KOHM, 1/10W 1 R614 ERJ6ENF3301 M 3.3KOHM, 1/10W 1 R615 ERJ6GEYJ102 M 1KOHM,J,1/10W 1 R616,17 ERJ6GEYJ103 M 10KOHM,J,1/10W 2 R618 ERJ6GEYJ104 M 100KOHM,J,1/10W 1 R619 ERJ8RQFR68 M 0.68OHM, J,1/8W 1 R620 ERJ6GEYJ103 M 10KOHM,J,1/10W 1 R621 ERJ8GEYJ123 M 12KOHM, J,1/8W 1 R622 ERJ8ENF1503 M 15KOHM, 1/8W 1 R624 D0C3R10KA004 M 10KOHM,J,1/3W 1 R626 ERJ8ENF1503 M 15KOHM, 1/8W 1 R627 ERJ6GEYJ752 M 7.5KOHM,J,1/10W 1 R628 EVMAASA00B33 控制 3KOHMB 1 R629 ERJ6GEYJ105 M 1MOHM,J,1/10W 1 R630 ERJ8GEYJ472 M 4.7KOHM, J,1/8W 1 R631 ERJ8GEYJ333 M 33KOHM, J,1/8W 1 R632 ERJ6GEYJ221 M 220 OHM,J,1/10W 1 R633 ERJ6GEYJ105 M 1MOHM,J,1/10W 1 R634 ERJ8RQJR39 M0.39 OHM, 1/8W 1 R636 ERJ8ENF1503 M 15KOHM, 1/8W 1 R637 ERJ8RQJR39 M0.39 OHM, 1/8W 1 R638 ERJ6GEYJ102 M 1KOHM,J,1/10W 1 R639,40 ERJ8RQJR39 M0.39 OHM, 1/8W 2 R641 ERJ6GEYJ473 M 47KOHM,J,1/10W 1 R642-44 ERJ8RQJR39 M0.39 OHM, 1/8W 3 R645 ERJ6GEYJ101 M 100 OHM,J,1/10W 1 R646,47 ERJ8GEYJ223 M 22KOHM, J,1/8W 2 R648 ERJ8ENF1503 M 15KOHM, 1/8W 1 R649 ERJ6GEYJ223 M 22KOHM,J,1/10W 1 R650 ERJ6GEYJ103 M 10KOHM,J,1/10W 1 R651,52 ERJ6ENF1002 M 10KOHM, 1/10W 2 R653 ERJ6ENF3302 M 33KOHM, 1/10W 1 R654 ERJ8GEYJ220 M 22 OHM, J,1/8W 1 R655 ERJ8RSJR16V M 16 OHM, 1/8W 1 R656 ERJ6ENF4702 M 47KOHM, 1/10W 1 R657 ERJ6GEYJ102 M 1KOHM,J,1/10W 1 R658 ERJ6GEYJ105 M 1MOHM,J,1/10W 1 R659 ERJ6ENF3002 M 30KOHM, 1/10W 1 R660 ERJ6ENF1202 M 12KOHM, 1/10W 1 R661 EVMEASA00B53 控制 5KOHMB 0.3W 1 R662 ERJ6ENF1503 M 150KOHM, 1/10W 1 R664 ERJ6ENF9101 M 9.1KOHM, 1/10W 1 R665 EVMEASA00B23 控制 2KOHMB 0.3W 1 R666 ERJ6GEYJ102 M 1KOHM,J,1/10W 1 R667,68 ERJ8GEY0R00 M 0 OHM, 1/8W 2 R669 ERJ6ENF1303 M 130KOHM, 1/10W 1 参考号 部品号 部品名称 & 说明 件数 备注 R670 ERJ6GEYJ102 M 1KOHM,J,1/10W 1 R671 EVMEASA00B14 控制 10KOHMB 0.3W 1 R672,73 ERJ6GEYJ102 M 1KOHM,J,1/10W 2 R674 ERJ8GEYJ333 M 33KOHM, J,1/8W 1 R675 ERJ6ENF2202 M 2.2KOHM, 1/10W 1 R676 ERJ8GEYJ333 M 33KOHM, J,1/8W 1 R677 ERJ6GEYJ474 M 470KOHM,J,1/10W 1 R678 ERJ8GEY0R00 M 0 OHM, 1/8W 1 R679,80 ERJ8RSJR16V M 16 OHM, 1/8W 2 R682 ERJ6ENF2002 M 20KOHM, 1/10W 1 R683 ERJ6GEYJ333 M 33KOHM,J,1/10W 1 R684 ERJ6GEYJ103 M 10KOHM,J,1/10W 1 R685,86 ERJ6GEYJ102 M 1KOHM,J,1/10W 2 R687 ERJ6GEYJ103 M 10KOHM,J,1/10W 1 R688,89 ERJ6GEYJ102 M 1KOHM,J,1/10W 2 R690 ERJ6GEYJ4R7 M 4.7 OHM,J,1/10W 1 R691 ERJ6GEYJ104 M 100KOHM,J,1/10W 1 R692 ERJ6GEYJ472 M 4.7KOHM,J,1/10W 1 R693 ERJ6GEYJ103 M 10KOHM,J,1/10W 1 R695 ERJ6ENF1602 M 16KOHM, 1/10W 1 R696 ERJ8GEYJ100 M 10 OHM, J,1/8W 1 R697 ERJ6GEYJ4R7 M 4.7 OHM,J,1/10W 1 R698 ERJ8RSJR16V M 16 OHM, 1/8W 1 R700-08 ERJ8GEYJ105 M 1MOHM, J,1/8W 9 R711 ERJ8RSJR16V M 16 OHM, 1/8W 1 R712 ERJ6GEYJ4R7 M 4.7 OHM,J,1/10W 1 R713 ERJ8GEYJ472 M 4.7KOHM, J,1/8W 1 R714 ERJ6GEYJ101 M 100 OHM,J,1/10W 1 R715 ERDS2TJ101 C 100 OHM, J,1/4W 1 R921 ERJ6RBD3302 M 33KOHM,F,1/10W 1 R922 ERJ6GEYJ101 M 100 OHM,J,1/10W 1 R931 ERJ6ENF3002 M 30KOHM, 1/10W 1 R932 ERJ6GEYJ104 M 100KOHM,J,1/10W 1 R933 ERJ6GEYJ102 M 1KOHM,J,1/10W 1 R935 ERJ6GEYJ104 M 100KOHM,J,1/10W 1 R936 ERJ6GEYJ103 M 10KOHM,J,1/10W 1 R937 ERJ6GEYJ102 M 1KOHM,J,1/10W 1 R938 ERJ6GEYJ472 M 4.7KOHM,J,1/10W 1 R939,40 ERJ6GEYJ102 M 1KOHM,J,1/10W 2 R943 ERJ6GEYJ105 M 1MOHM,J,1/10W 1 R945 ERJ6GEYJ223 M 22KOHM,J,1/10W 1 R946 ERJ6GEYJ333 M 33KOHM,J,1/10W 1 R947 ERJ8GEYJ331 M 330 OHM, J,1/8W 1 R950 ERJ6GEYJ105 M 1MOHM,J,1/10W 1 R951,52 ERJ8GEYJ100 M 10 OHM, J,1/8W 2 R953 ERJ6GEYJ222 M 2.2KOHM,J,1/10W 1 R955 ERJ6GEYJ473 M 47KOHM,J,1/10W 1 R956 ERJ6GEYJ104 M 100KOHM,J,1/10W 1 RL402,03 TSEH8011 继电器 2 S401,02 J0LT00000009 开关 2 T401 G4D4A0000117 转接变压器 1 T402 G4D1A0000098 转接变压器 1 T404 ETS42LA12GAD 转接变压器 1 T407 ETQ11K5AZ CHOKE TRANS 1 T410 ETS25AF115AH 转接变压器 1 T601 G4D2A0000264 转接变压器 1 W9,10 J0JKB0000037 平核 2 X501 H2B400400021 晶体 1 Z1,Z2 K4ZZ01000206 端子 2 Z420 TMM23417 线夹 2 Z450-53 EYF52BCY 熔丝架 4 ZN401 ERZVGED621T2 变阻器 1 ZN402 D4EAD7510001 变阻器 1 ZN404 ERZVGAD681T2 变阻器 1 ZN406 ERZVA7D511 变阻器 1 参考号 部品号 部品名称 & 说明 件数 备注
