ORDER NO. PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A. PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936 PIONEER CORPORATION 2008 DEH-P410UB/XS/UC CRT4237 CD RECEIVER DEH-P410UB/XS/UC DEH-P4100UB/XS/UC DEH-P4150UB/XS/ES This service manual should be used together with the following manual(s): Model No. Order No. Mech.Module Remarks CX-3240 CRT4050 S10.5COMP2-iPod/USB CD Mech. Module : Circuit Descriptions, Mech. Descriptions, Disassembly For details, refer to "Important Check Points for Good Servicing". K-ZZZ. OCT. 2008 Printed in Japan www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-P410UB/XS/UC 2 1 2 3 4 1 2 3 4 C D F A B E SAFETY INFORMATION CAUTION WARNING Where in a manufacturer’s service documentation, for example in circuit diagrams or lists of components, a symbol is used to indicate that a specific component shall be replaced only by the component specified in that documentation for safety reasons, the following symbol shall be used: This product contains certain electrical parts contain chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. Health & Safety Code Section 25249.6 - Proposition 65 This service manual is intended for qualified service technicians; it is not meant for the casual do-it-yourselfer. Qualified technicians have the necessary test equipment and tools, and have been trained to properly and safety repair complex products such as those covered by this manual. Improperly performed repairs can adversely affect the safety and reliability of the product and may void the warranty. If you are not qualified to perform the repair of this product properly and safety, you should not risk trying to do so and refer the repair to a qualified service technician. CAUTION: USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE. - Safety Precautions for those who Service this Unit. When checking or adjusting the emitting power of the laser diode exercise caution in order to get safe, reliable results. Caution: 1. During repair or tests, minimum distance of 13 cm from the focus lens must be kept. CAUTION CLASS 1M INVISIBLE LASER RADIATION WHEN OPEN. DO NOT VIEW DIRECTLY WITH OPTICAL INSTRUMENTS 2. During repair or tests, do not view laser beam for 10 seconds or longer. CAUTION Danger of explosion if battery is incorrectly replaced. Replaced only with the same or equivalent type recommended by the manufacture. Discord used batteries according to the manufacture's instructions. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-P410UB/XS/UC 3 5 6 7 8 5 6 7 8 C D F A B E [Important Check Points for Good Servicing] In this manual, procedures that must be performed during repairs are marked with the below symbol. Please be sure to confirm and follow these procedures. 1. Product safety Please conform to product regulations (such as safety and radiation regulations), and maintain a safe servicing environment by following the safety instructions described in this manual. 1 Use specified parts for repair. Use genuine parts. Be sure to use important parts for safety. 2 Do not perform modifications without proper instructions. Please follow the specified safety methods when modification(addition/change of parts) is required due to interferences such as radio/TV interference and foreign noise. 3 Make sure the soldering of repaired locations is properly performed. When you solder while repairing, please be sure that there are no cold solder and other debris. Soldering should be finished with the proper quantity. (Refer to the example) 4 Make sure the screws are tightly fastened. Please be sure that all screws are fastened, and that there are no loose screws. 5 Make sure each connectors are correctly inserted. Please be sure that all connectors are inserted, and that there are no imperfect insertion. 6 Make sure the wiring cables are set to their original state. Please replace the wiring and cables to the original state after repairs. In addition, be sure that there are no pinched wires, etc. 7 Make sure screws and soldering scraps do not remain inside the product. Please check that neither solder debris nor screws remain inside the product. 8 There should be no semi-broken wires, scratches, melting, etc. on the coating of the power cord. Damaged power cords may lead to fire accidents, so please be sure that there are no damages. If you find a damaged power cord, please exchange it with a suitable one. 9 There should be no spark traces or similar marks on the power plug. When spark traces or similar marks are found on the power supply plug, please check the connection and advise on secure connections and suitable usage. Please exchange the power cord if necessary. a Safe environment should be secured during servicing. When you perform repairs, please pay attention to static electricity, furniture, household articles, etc. in order to prevent injuries. Please pay attention to your surroundings and repair safely. 2. Adjustments To keep the original performance of the products, optimum adjustments and confirmation of characteristics within specification. Adjustments should be performed in accordance with the procedures/instructions described in this manual. 4. Cleaning For parts that require cleaning, such as optical pickups, tape deck heads, lenses and mirrors used in projection monitors, proper cleaning should be performed to restore their performances. 3. Lubricants, Glues, and Replacement parts Use grease and adhesives that are equal to the specified substance. Make sure the proper amount is applied. 5. Shipping mode and Shipping screws To protect products from damages or failures during transit, the shipping mode should be set or the shipping screws should be installed before shipment. Please be sure to follow this method especially if it is specified in this manual. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-P410UB/XS/UC 4 1 2 3 4 1 2 3 4 C D F A B E CONTENTS SAFETY INFORMATION..................................................................................................................................... 2 1. SERVICE PRECAUTIONS............................................................................................................................... 5 1.1 SERVICE PRECAUTIONS ........................................................................................................................ 5 1.2 NOTES ON SOLDERING .......................................................................................................................... 5 2. SPECIFICATIONS............................................................................................................................................ 6 2.1 SPECIFICATIONS ..................................................................................................................................... 6 2.2 DISC/CONTENT FORMAT ........................................................................................................................ 9 2.3 PANEL FACILITIES.................................................................................................................................. 10 2.4 CONNECTION DIAGRAM ....................................................................................................................... 16 3. BASIC ITEMS FOR SERVICE........................................................................................................................ 18 3.1 CHECK POINTS AFTER SERVICING..................................................................................................... 18 3.2 PCB LOCATIONS .................................................................................................................................... 19 3.3 JIGS LIST ................................................................................................................................................ 19 3.4 CLEANING............................................................................................................................................... 19 4. BLOCK DIAGRAM.......................................................................................................................................... 20 5. DIAGNOSIS.................................................................................................................................................... 22 5.1 OPERATIONAL FLOWCHART................................................................................................................ 22 5.2 ERROR CODE LIST ................................................................................................................................ 23 5.3 CONNECTOR FUNCTION DESCRIPTION............................................................................................. 25 6. SERVICE MODE ............................................................................................................................................ 26 6.1 DISPLAY TEST MODE ............................................................................................................................ 26 6.2 CD TEST MODE...................................................................................................................................... 27 7. DISASSEMBLY .............................................................................................................................................. 29 8. EACH SETTING AND ADJUSTMENT ........................................................................................................... 32 8.1 CD ADJUSTMENT................................................................................................................................... 32 8.2 CHECKING THE GRATING AFTER CHANGING THE PICKUP UNIT.................................................... 33 8.3 PCL OUTPUT CONFIRMATION.............................................................................................................. 35 9. EXPLODED VIEWS AND PARTS LIST.......................................................................................................... 36 9.1 PACKING ................................................................................................................................................. 36 9.2 EXTERIOR (1) ......................................................................................................................................... 38 9.3 EXTERIOR (2) ......................................................................................................................................... 40 9.4 CD MECHANISM MODULE..................................................................................................................... 42 10. SCHEMATIC DIAGRAM............................................................................................................................... 44 10.1 TUNER AMP ASSY(GUIDE PAGE)....................................................................................................... 44 10.2 KEYBOARD UNIT.................................................................................................................................. 50 10.3 CD MECHANISM MODULE(GUIDE PAGE).......................................................................................... 52 10.4 WAVEFORMS........................................................................................................................................ 58 11. PCB CONNECTION DIAGRAM.................................................................................................................... 62 11.1 TUNER AMP ASSY................................................................................................................................ 62 11.2 KEYBOARD UNIT.................................................................................................................................. 66 11.3 CD CORE UNIT(S10.5 iPod-Code2 Class4).......................................................................................... 68 12. ELECTRICAL PARTS LIST .......................................................................................................................... 70 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-P410UB/XS/UC 5 5 6 7 8 5 6 7 8 C D F A B E 1. SERVICE PRECAUTIONS 1.1 SERVICE PRECAUTIONS 1.2 NOTES ON SOLDERING 1. You should conform to the regulations governing the product (safety, radio and noise, and other regulations), and should keep the safety during servicing by following the safety instructions described in this manual. 2. Before disassembling the unit, be sure to turn off the power. Unplugging and plugging the connectors during power-on mode may damage the ICs inside the unit. 3. To protect the pickup unit from electrostatic discharge during servicing, take an appropriate treatment (shorting-solder) by referring to "the DISASSEMBLY". 4. After replacing the pickup unit, be sure to check the grating. 5. Be careful in handling ICs. Some ICs such as MOS type are so fragile that they can be damaged by electrostatic induction. For environmental protection, lead-free solder is used on the printed circuit boards mounted in this unit. Be sure to use lead-free solder and a soldering iron that can meet specifications for use with lead-free solders for repairs accompanied by reworking of soldering. Compared with conventional eutectic solders, lead-free solders have higher melting points, by approximately 40 C. Therefore, for lead-free soldering, the tip temperature of a soldering iron must be set to around 373 C in general, although the temperature depends on the heat capacity of the PC board on which reworking is required and the weight of the tip of the soldering iron. Compared with eutectic solders, lead-free solders have higher bond strengths but slower wetting times and higher melting temperatures (hard to melt/easy to harden). The following lead-free solders are available as service parts: Parts numbers of lead-free solder: GYP1006 1.0 in dia. GYP1007 0.6 in dia. GYP1008 0.3 in dia. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-P410UB/XS/UC 6 1 2 3 4 1 2 3 4 C D F A B E 2. SPECIFICATIONS 2.1 SPECIFICATIONS DEH-P410UB/XS/UC, DEH-P4100UB/XS/UC General Power source..........................14.4 V DC (10.8 V to 15.1 V allowable) Grounding system.................Negative type Max. current consumption ...............................................10.0 A Dimensions (W × H × D): DIN Chassis.................. 178 mm × 50 mm × 162 mm (7 in. × 2 in. × 6-3/8 in.) Nose........................ 188 mm × 58 mm × 24 mm (7-3/8 in.× 2-1/4 in.× 1 in.) D Chassis.................. 178 mm × 50 mm × 162 mm (7 in.× 2 in.× 6-3/8 in.) Nose........................ 170 mm × 46 mm × 24 mm (6-3/4 in.× 1-3/4 in.× 1 in.) Weight ..................................... 1.3 kg(2.9 lbs) Audio Maximum power output ...... 50 W × 4 50 W × 2/4 + 70 W × 1/2 (for subwoofer) Continuous power output .. 22 W × 4 (50 Hz to 15 000 Hz, 5% THD, 4 load, both channels driven) Load impedance................... 4 to 8 × 4 4 to 8 × 2 + 2 × 1 Preout max output level ...... 4 V Equalizer (3-Band Parametric Equalizer): Low Frequency.............. 40/80/100/160 Hz Q Factor .................0.35/0.59/0.95/1.15 (+6 dB when boosted) Gain......................... ±12 dB Mid Frequency.............. 200/500/1k/2k Hz Q Factor .................0.35/0.59/0.95/1.15 (+6 dB when boosted) Gain......................... ±12 dB High Frequency.............. 3.15k/8k/10k/12.5k Hz Q Factor .................0.35/0.59/0.95/1.15 (+6 dB when boosted) Gain......................... ±12 dB HPF: Frequency.......................50/63/80/100/125 Hz Slope................................–12 dB/oct Subwoofer (mono): Frequency.......................50/63/80/100/125 Hz Slope............................... – 18 dB/oct Gain................................. + 6 dB to – 24 dB Phase ..............................Normal/Reverse Bass boost: Gain................................. +12 dB to 0 dB CD player System.....................................Compact disc audio system Usable discs .......................... Compact disc Signal-to-noise ratio............ 94 dB (1 kHz) (IHF-A net- work) Number of channels ............ 2 (stereo) MP3 decoding format ..........MPEG-1 & 2 Audio Layer 3 WMA decoding format ........ Ver. 7,7.1, 8, 9, 10, 11 (2ch audio) (Windows Media Player) AAC decoding format...........MPEG-4 AAC (iTunes en- coded only) (.m4a) (Ver. 7.2 and earlier) WAV signal format................Linear PCM & MS ADPCM USB Specification .......................... USB 2.0full speed Supply current ....................... 500 mA Maximum amount of memory .............................................. 250 GB File system............................. FAT16, FAT32 MP3 decoding format ......... MPEG-1 & 2 Audio Layer 3 WMA decoding format ........ Ver. 7,7.1, 8, 9, 10, 11 (2ch audio) (Windows Media Player) AAC decoding format...........MPEG-4 AAC (iTunes en- coded only) (.m4a) (Ver. 7.2 and earlier) WAV signal format................Linear PCM & MS ADPCM FM tuner Frequency range................... 87.9 MHz to 107.9 MHz Usable sensitivity.................. 8 dBf (0.7 μV/75 , mono, S/N: 30 dB) Signal-to-noise ratio............. 75 dB (IHF-A network) AM tuner Frequency range................... 530 kHz to 1 710 kHz (10 kHz) Usable sensitivity.................. 18 μV(S/N: 20 dB) Signal-to-noise ratio............. 65 dB (IHF-A network) Backup current .......................5 mA or less www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-P410UB/XS/UC 7 5 6 7 8 5 6 7 8 C D F A B E CEA2006 Specifications Power output ......................... 14 W RMS × 4 Channels (4 and 1 % THD+N) S/N ratio .................................. 91 dBA (reference: 1 W into 4 ) Note Specifications and the design are subject to mod- ifications without notice due to improvements. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-P410UB/XS/UC 8 1 2 3 4 1 2 3 4 C D F A B E DEH-P4150UB/XS/ES General Rated power source..............14.4 V DC (allowable voltage range: 12.0 V to 14.4 V DC) Grounding system.................Negative type Max. current consumption ................................................10.0 A Dimensions (W × H × D): DIN Chassis.................. 178 mm × 50 mm × 162 mm Nose........................ 188 mm × 58 mm × 24 mm D Chassis.................. 178 mm × 50 mm × 162 mm Nose........................ 170 mm × 46 mm × 24 mm Weight ..................................... 1.3 kg Audio Maximum power output ...... 50 W × 4 50 W × 2/4 + 70 W × 1/2 (for subwoofer) Continuous power output .. 22 W × 4 (50 Hz to 15 000 Hz, 5% THD, 4 load, both channels driven) Load impedance................... 4 to 8 × 4 4 to 8 × 2 + 2 × 1 Preout max output level ...... 4 V Equalizer (3-Band Parametric Equalizer): Low Frequency.............. 40/80/100/160 Hz Q Factor .................0.35/0.59/0.95/1.15 (+6 dB when boosted) Gain......................... ±12 dB Mid Frequency.............. 200/500/1k/2k Hz Q Factor .................0.35/0.59/0.95/1.15 (+6 dB when boosted) Gain......................... ±12 dB High Frequency.............. 3.15k/8k/10k/12.5k Hz Q Factor .................0.35/0.59/0.95/1.15 (+6 dB when boosted) Gain......................... ±12 dB HPF: Frequency.......................50/63/80/100/125 Hz Slope................................–12 dB/oct Subwoofer (mono): Frequency...................... 50/63/80/100/125 Hz Slope............................... –18 dB/oct Gain.................................. +6 dB to –24 dB Phase ..............................Normal/Reverse Bass boost: Gain.................................. +12 dB to 0 dB CD player System.....................................Compact disc audio system Usable discs .......................... Compact disc Signal-to-noise ratio............. 94 dB (1kHz) (IEC-A net- work) Number of channels ............ 2 (stereo) MP3 decoding format ......... MPEG-1 & 2 Audio Layer 3 WMA decoding format ....... Ver. 7, 7.1, 8, 9, 10, 11 (2ch audio) (Windows Media Player) AAC decoding format...........MPEG-4 AAC (iTunes en- coded only) (.m4a) (Ver. 7.2 and earlier) WAV signal format................Linear PCM & MS ADPCM USB Specification .......................... USB 2.0full speed Supply current ....................... 500 mA Maximum amount of memory .............................................. 250 GB File system............................. FAT16, FAT32 MP3 decoding format ......... MPEG-1 & 2 Audio Layer 3 WMA decoding format ....... Ver. 7, 7.1, 8, 9, 10, 11 (2ch audio) (Windows Media Player) AAC decoding format...........MPEG-4 AAC (iTunes en- coded only) (.m4a) (Ver. 7.2 and earlier) WAV signal format................Linear PCM & MS ADPCM FM tuner Frequency range................... 87.5 MHz to 108.0 MHz Usable sensitivity.................. 8 dBf (0.7 μV/75 , mono, S/N: 30 dB) Signal-to-noise ratio............. 75 dB (IEC-A network) AM tuner Frequency range................... 531 kHz to 1 602 kHz (9 kHz) 530 kHz to 1 640 kHz (10 kHz) Usable sensitivity.................. 18 μV(S/N: 20 dB) Signal-to-noise ratio............. 65 dB (IEC-A network) Infrared remote control Wavelength............................. 940 nm ±50 nm Output ......................................typ; 12 mw/sr per Infrared LED Note Specifications and the design are subject to mod- ifications without notice due to improvements. Backup current ....................... 5 mA or less www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-P410UB/XS/UC 9 5 6 7 8 5 6 7 8 C D F A B E 2.2 DISC/CONTENT FORMAT * Depends on the version of Windows Media Player 11 used to encode WMA files, the noise may appear. Then, if you update the version, the noise will be solved. * www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-P410UB/XS/UC 10 1 2 3 4 1 2 3 4 C D F A B E 2.3 PANEL FACILITIES DEH-P410UB/XS/UC, DEH-P4100UB/XS/UC What ’s what Head unit 1 LIST button Press to display the disc title list, track title list, folder list, file list or preset channel list depending on the source. 2 SOURCE/OFF button This unit is turned on by selecting a source. Press to cycle through all the available sources. 3 S.Rtrv/SAT MODE button Press to switch Sound Retriever settings. When XM tuner or SIRIUS tuner is selected as the source, press to change the channel select mode. 4 MULTI-CONTROL Move to perform manual seek tuning, fast forward, reverse and track search controls. Also used for controlling functions. Turn to increase or decrease the volume. 5 SW/BASS button Press to switch to subwoofer setting menu. When operating subwoofer menu, press to switch menu. Press and hold to switch to bass boost menu. 6 EJECT button Press to eject a disc. 7 DETACH button Press to remove the front panel from the head unit. 8 AUX input jack (3.5 mm stereo jack) Use to connect an auxiliary device. 9 CLOCK button Press to change to the clock display. a RPT/LOCAL button Press to switch the repeat play range while using CD, USB or iPod. Press to switch local settings while using tuner as the source. b RDM/iPod button Press to turn random function on or off while using CD or USB. While using an iPod, press to shuffle all tracks. Press and hold to switch the control mode while using an iPod. If using the iPod with an interface adapter (CD-IB100 ), press to switch the shuffle function. c DISP/BACK/SCRL button Press to select different displays. Press and hold to scroll through the text in- formation. 1 c d 2 3 4 6 5 9 8 7 a b www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-P410UB/XS/UC 11 5 6 7 8 5 6 7 8 C D F A B E Press to return to the previous display when operating the menu. Press and hold to return to the main menu when operating the menu. d BAND/ESC button Press to select among three FM bands and one AM band. Press to return to the ordinary display when operating the menu. Remote control Operation is the same as when using the but- tons on the head unit. e VOLUME buttons Press to increase or decrease the volume. f MUTE button Press to turn off the sound. To turn on the sound, press again. g / / / buttons Press to perform manual seek tuning, fast forward, reverse and track search controls. Also used for controlling functions. h AUDIO button Press to select an audio function. i DISP button Press to select different displays. Press and hold to scroll through the text in- formation. j button Press to turn pause on or off. k FUNCTION button Press to select functions. l LIST/ENTER button Press to display the disc title list, track title list, folder list, file list or preset channel list depending on the source. While in the operating menu, press to con- trol functions. Display indication 1 Main display section Displays band, frequency, elapsed playback time and other settings. • Tuner Band and frequency are displayed. • Built-in CD player, USB, iPod Elapsed playback time and literal infor- mation are displayed. 2 S.Rtrv indicator Appears when Sound Retriever function is on. 3 indicator Appears when an upper tier of folder or menu exists. 4 (folder) indicator Appears when operating list function. 5 indicator Appears when a lower tier of folder or menu exists. 6 (artist) indicator Appears when the disc (track) artist name is displayed on the main display section. Appears when artist search refinement on the iPod browsing function is in use. 7 (disc) indicator Appears when the disc (album) name is dis- played on the main display section. Appears when album search refinement on the iPod browsing function is in use. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-P410UB/XS/UC 12 1 2 3 4 1 2 3 4 C D F A B E 8 (song) indicator Appears when the track (song) name is dis- played on the main display section. Appears when song search refinement on the iPod browsing function is in use. 9 (subwoofer) indicator Appears when subwoofer is on. a LOC indicator Appears when local seek tuning is on. b (stereo) indicator Appears when the selected frequency is being broadcast in stereo. c (shuffle) indicator Appears when shuffle function is on while iPod source is being selected. d F-REPEAT indicator Appears when folder repeat is on. When repeat function is on, only REPEATis displayed. e F-RANDOM indicator Appears when folder random is on. When random function is on, only RANDOM is displayed. f (loudness) indicator Appears when loudness is on. g (iPod connection) indicator Appears when the iPod connection is recog- nized while USB source is being selected. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-P410UB/XS/UC 13 5 6 7 8 5 6 7 8 C D F A B E DEH-P4150UB/XS/ES What ’s what Head unit 1 LIST button Press to display the disc title list, track title list, folder list, file list or preset channel list depending on the source. 2 SOURCE/OFF button This unit is turned on by selecting a source. Press to cycle through all the available sources. 3 S.Rtrv button Press to switch Sound Retriever settings. 4 MULTI-CONTROL Move to perform manual seek tuning, fast forward, reverse and track search controls. Also used for controlling functions. Turn to increase or decrease the volume. 5 SW/BASS button Press to switch to subwoofer setting menu. When operating subwoofer menu, press to switch menu. Press and hold to switch to bass boost menu. 6 EJECT button Press to eject a disc. 7 DETACH button Press to remove the front panel from the head unit. 8 AUX input jack (3.5 mm stereo jack) Use to connect an auxiliary device. 9 CLOCK button Press to change to the clock display. a RPT/LOCAL button Press to switch the repeat play range while using CD, USB or iPod. Press to switch local settings while using tuner as the source. b RDM/iPod button Press to turn random function on or off while using CD or USB. While using an iPod, press to shuffle all tracks. Press and hold to switch the control mode while using an iPod. If using the iPod with an interface adapter (CD-IB100 ), press to switch the shuffle function. c DISP/BACK/SCRL button Press to select different displays. Press and hold to scroll through the text in- formation. Press to return to the previous display when operating the menu. 1 c d 2 3 4 6 5 9 8 7 a b www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-P410UB/XS/UC 14 1 2 3 4 1 2 3 4 C D F A B E Press and hold to return to the main menu when operating the menu. d BAND button Press to select among three FM bands and one AM band. Press to return to the ordinary display when operating the menu. Remote control Operation is the same as when using the but- tons on the head unit. e VOLUME buttons Press to increase or decrease the volume. f MUTE button Press to turn off the sound. To turn on the sound, press again. g / / / buttons Press to perform manual seek tuning, fast forward, reverse and track search controls. Also used for controlling functions. h AUDIO button Press to select an audio function. i DISP button Press to select different displays. Press and hold to scroll through the text in- formation. j button Press to turn pause on or off. k FUNCTION button Press to select functions. l LIST/ENTER button Press to display the disc title list, track title list, folder list, file list or preset channel list depending on the source. While in the operating menu, press to con- trol functions. Display indication 1 Main display section Displays band, frequency, elapsed playback time and other settings. • Tuner Band and frequency are displayed. • Built-in CD player, USB, iPod Elapsed playback time and literal infor- mation are displayed. 2 S.Rtrv indicator Appears when Sound Retriever function is on. 3 indicator Appears when an upper tier of folder or menu exists. 4 (folder) indicator Appears when operating list function. 5 indicator Appears when a lower tier of folder or menu exists. 6 (artist) indicator Appears when the disc (track) artist name is displayed on the main display section. Appears when artist search refinement on the iPod browsing function is in use. 7 (disc) indicator Appears when the disc (album) name is dis- played on the main display section. Appears when album search refinement on the iPod browsing function is in use. 8 (song) indicator Appears when the track (song) name is dis- played on the main display section. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-P410UB/XS/UC 15 5 6 7 8 5 6 7 8 C D F A B E Appears when song search refinement on the iPod browsing function is in use. 9 (subwoofer) indicator Appears when subwoofer is on. a LOC indicator Appears when local seek tuning is on. b (stereo) indicator Appears when the selected frequency is being broadcast in stereo. c (shuffle) indicator Appears when shuffle function is on while iPod source is being selected. d F-REPEAT indicator Appears when folder repeat is on. When repeat function is on, only REPEATis displayed. e F-RANDOM indicator Appears when folder random is on. When random function is on, only RANDOM is displayed. f (loudness) indicator Appears when loudness is on. g (iPod connection) indicator Appears when the iPod connection is recog- nized while USB source is being selected. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-P410UB/XS/UC 16 1 2 3 4 1 2 3 4 C D F A B E 2.4 CONNECTION DIAGRAM When not connecting a rear speaker lead to a subwoofer 36. Power amp (sold separately) 15. Yellow Connect to the constant 12 V supply terminal. 16. Red Connect to terminal controlled by ignition switch (12 V DC). 17. Orange/white Connect to lighting switch terminal. 35. Connect with RCA cables (sold separately) 39. Perform these connections when using the optional amplifier. 18. Black (chassis ground) Connect to a clean, paint-free metal location. 2. This product 9. Subwoofer output 8. Antenna jack 7. Front output 14. Fuse (10 A) 38. System remote control 24.Left 25.Right 37. Blue/white Connect to system control terminal of the power amp or auto-antenna relay control terminal (max. 300 mA 12 V DC). 31. With a 2 speaker system, do not connect anything to the speaker leads that are not connected to speakers. r e k a e p s t n o rF .3 2 r e k a e p s t n o rF .3 2 r e k a e p s r a e R .0 3 r e k a e p s r a e R .0 3 19. White 21. Gray 22. Gray/black 20. White/black 26. Green 28. Violet 27. Green/black 29. Violet/black 3. Rear output 40. Subwoofer 33. To front output 34. To subwoofer output 32. To rear output 40. Subwoofer 30. Rear speaker 30. Rear speaker r e k a e p s t n o rF .3 2 r e k a e p s t n o rF .3 2 11. IP-BUS input (Blue) 12. IP-BUS cable 13. Multi-CD player (sold separately) 1.5 m (4 ft. 9 in.) 1. USB cable Connect to separately sold USB device. 10. Wired remote input Hard-wired remote control adaptor can be connected (sold separately). 20 cm (7-7/8 in.) 4. iPod 5. Dock connector 6. Interface cable 50 cm (20 in.) 36. Power amp (sold separately) 36. Power amp (sold separately) DEH-P410UB/XS/UC www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-P410UB/XS/UC 17 5 6 7 8 5 6 7 8 C D F A B E When using a subwoofer without using the optional amplifier 24.Left 25.Right r e k a e p s t n o rF .3 2 r e k a e p s t n o rF .3 2 19. White 21. Gray 22. Gray/black 20. White/black 26. Green 28. Violet 24. Green/black 29. Violet/black 26. Green 28. Violet 27. Green/black 29. Violet/black 42. Subwoofer (4 4 ( r e f o o w b u S .2 4 ) ) 43. When using a subwoofer of 70 W (2 ), be sure to connect with Violet and Violet/black leads of this unit. Do not connect anything with Green and Green/black leads. 45. Subwoofer (4 ) x 2 44. Not used. 41.Note: Change the initial setting of this unit. The subwoofer output of this unit is monaural. 15. Yellow Connect to the constant 12 V supply terminal. 16. Red Connect to terminal controlled by ignition switch (12 V DC). 17. Orange/white Connect to lighting switch terminal. 18. Black (chassis ground) Connect to a clean, paint-free metal location. 37. Blue/white Connect to system control terminal of the power amp or auto-antenna relay control terminal (max. 300 mA 12 V DC). 2. This product 9. Subwoofer output 8. Antenna jack 7. Front output 14. Fuse (10 A) 3. Rear output 11. IP-BUS input (Blue) 12. IP-BUS cable 13. Multi-CD player (sold separately) 1. USB cable Connect to separately sold USB device. 20 cm (7-7/8 in.) 10. Wired remote input Hard-wired remote control adaptor can be connected (sold separately). 1.5 m (4 ft. 9 in.) 4. iPod 5. Dock connector 6. Interface cable 50 cm (20 in.) DEH-P410UB/XS/UC www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-P410UB/XS/UC 18 1 2 3 4 1 2 3 4 C D F A B E 3. BASIC ITEMS FOR SERVICE 3.1 CHECK POINTS AFTER SERVICING To keep the product quality after servicing, please confirm following check points. d e m rif n o c e b o t m e tI s e r u d e c o r P . o N 1 Confirm whether the customer complain has been solved. If the customer complain occurs with the specific media, use it for the operation check. The customer complain must not be reappeared. Display, audio and operations must be normal. 2 CD Play back a CD. (Track search) No malfunction on display, audio and operation. 3 FM/AM tuner Check FM/AM tuner action. (Seek, Preset) Switch band to check both FM and AM. Display, audio and operations must be normal. 4 Check whether no disc is inside the product. The media used for the operating check must be ejected. r e tf a e c n a r a e p p a sti n o trid r o s e h ct a r c s o N k c e h c e c n a r a e p p A 5 receiving it for service. See the table below for the items to be checked regarding audio: Item to be checked regarding audio Distortion Noise Volume too low Volume too high Volume fluctuating Sound interrupted www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-P410UB/XS/UC 19 5 6 7 8 5 6 7 8 C D F A B E 3.2 PCB LOCATIONS 3.3 JIGS LIST 3.4 CLEANING A B Keyboard Unit CD Core Unit (S10.5 iPod-Code2 Class4) C Tuner Amp Unit Unit Number : YWM5394(P410UB) Unit Number : YWM5392(P4100UB) Unit Number : YWM5396(P4150UB) Unit Name : Tuner Amp Assy Unit Number : (P410UB) Unit Number : (P4100UB) Unit Number : (P4150UB) Unit Name : Keyboard Unit Unit Number : CWX3712 Unit Name : CD Core Unit(S10.5 iPod-Code2 Class4) - Jigs List Name Test Disc L.P.F. Jig No. TCD-782 Remarks Checking the grating Checking the grating (Two pieces) Name Jig No. Remarks - Grease List Name Grease Grease Grease No. GEM1024 GEM1045 Remarks CD Mechanism Module CD Mechanism Module Name Grease No. Remarks Before shipping out the product, be sure to clean the following portions by using the prescribed cleaning tools: Portions to be cleaned Cleaning tools CD pickup lenses Cleaning liquid : GEM1004 Cleaning paper : GED-008 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-P410UB/XS/UC 20 1 2 3 4 1 2 3 4 C D F A B E 4. BLOCK DIAGRAM PICKUP UNIT (P10.5)(SERVICE) CD CORE UNIT(S10.5 iPod-Code2 Class4) C BRST,BRXEN,BSRQ CN701 Q101 M LD MD S903 DSCSNS SPINDLE MOTOR M LOADING/CARRIAGE MOTOR LD- MD 15 5 HOLOGRAM UNIT IC301 BA5839FP IC201 PE5675A RF AMP, CD DECODER, MP3&WMA DECODER DIGITAL SERVO/DATA•PROCESSOR CPU, USB HOST CONTROLLER ACTUATOR/ MOTOR DRIVER 2 VD VD 13 LOUT 9 CN101 16 SOP 15 SOM 18 LCOP 17 LCOM 21 CLCONT 55 LOUT 9 CONT TD,FD AC,BD,E,F SD,MD S901 HOME S904 12EJ S905 8EJ LD+ 14 141 LD 142 PD 12EJ CONT CLCONT HOME 8 9 20 41 VDD 1 VDD2 BDATA,BSCK Q201 17 /ADENA VDD 15 5 FOCUS ACT. TRACKING ACT. FOP TOP 2 1 TOP FOP 11 FOP 14 TOP 2 1 14 8EJ 7 DSCSNS 10 VDD3 16 /RESET 8 /RESET 8 8 VREF REFO 133 REFOUT 3 3 FOM FOM 12 FOM 4 4 TOM TOM 13 TOM 22 LOEJ LOEJ 28 52 50 X201 XTAL /XTAL 16.93MHz VDSENS 11 VD 16 17 DP DM 4 5 DM DP 2 1 X205 48MHz USBXTAL /USBXTAL VDD2 Q102 39 /PUEN VCC VDD2 IC205 341S2162 iPod AUTHENTICATION COPROCESSOR CPRST SDA,SCL ASENBO 41 MUTE 49 40 30 29 54 SYSTEM CONTROLLER IC 601(2/2) PEG407B CN401 1 2,3 TX RX IPPW SWVDD TUNER AMP UNIT TU BU BU CD 35 DPDT 36 KYDT 51 ILMPW A B- B14 B+ IN1+ CN101 IN1- IP-BUS DRIVER IC101 HA12241FP 1 2 8 6 5 B.UP Q101 VDD ANTENNA 50 OELPW V CN701 VDD VDD3.3V 19 DSENS CDL Q102 CD VD VD VDCONT B.UP Q702 Q701 BRST,BRXEN,BSRQ,BDATA,BSCK 11 7 18 12 CDRST 19 25 1 2 3 CN251 USDM USDP 28 24 SYNC USBCTL FLG B.UP IC702 NJM2885DL1-33 CD3.3V REGULATOR 3 1 CDRST 23 22 VCC 7 1 EN VIN SW 2 IC251 R5523N001B IC501 BD9781HFP USB5V 1 EN 3 FLG 4 VIN 5 VOUT US5V 3 4 DP DM CDVDD SYSPW 48 A USB 7 11 5 1 8 IP BUS B. BUS- BUS+ DIN1 ROUT STBY 21 RX2 TUNPDO TUNPCK TUNPDI CE1 CE2 SL FMRF ANT adj RF adj FM ANT T51 CF52 RFGND OSCGND DGND AUDIOGND NC VCC VDD_3.3 3.3V 2.5V IC4 3.3V 2.5V IC2 2.5V NC CE2 ROM_VDD SL DI CK CE1 DO 7 6 13 5 10 9 8 11 14 18 19 20 21 1 3 2 12 15 22 16 4 17 IC1 3.3V AM ANT FMRF ATT LPF OSC IC3 EEPROM 5.0V IC5 5V 3.3V ATT MIXER, IF AMP DET, FM MPX, 23 Lch NC NC NC NC NC → → FM/AM TUNER UNIT www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-P410UB/XS/UC 21 5 6 7 8 5 6 7 8 C D F A B E BSENS ASENS B.UP 75 18 O 10 Front_L 11 Rear_L 41 MUTE ILM+ SWVDD 21 23 5 3 FL+ FL- RL+ RL- ACC IN2_L 49 IN4+_L 3 IN4-_L 4 IN1_L 7 FLIN 14 RLIN VCC 12 6,20 22 4 AMP SYSTEM ONTROLLER C 601(2/2) PEG407B IC151 PML018A IC301 PAL007C VDD Q911 Q931 ELECTRONIC VOLUME/ SOURCE SELECTOR SWVDD STBY MUTE Q851 Q852 VST,VCK,VDT TUNL BUSL+ BUSL- CDL DPDT 35 DPDT 36 KYDT KYDT MUTE Q451 RCRL SWL Q351 Pre/SW_L 51 ILMPW MUTE Q453 SYSTEM CONTROLLER IC 601(1/2) PEG407B 25 B.REM VDD REGULATOR BSENS ASENS CN901 B.UP CN351 DALMON 47 Q352 RL SWL ISENS 53 50 OELPW B.UP VDD CN803 OELB 19 DSENS 4 ILM GND B.UP T FL+ FL1 FL- FL2 RL+ RL1 RL- RL2 BREM 14 6 8 7 5 16 11 15 12 1 IN5-_L 6 AUXL L ILM DSENS SWVDD 12 2 PEE 26 BZ601 BUZZER 12V REGULATOR Q182 Q181 XIN XOUT 15 X601 15MHz 13 OELB OELB VP 13 IC401 NJM2885DL1-33 1 3 VCC 3.3V REGULATOR VDD3.3V 1 2 4 B.UP VCC8.4V REGULATOR IC921 NJM2388F84 VCC Q353 6 MUTE RCFL FL IN5+_L 2 SYSPW 48 AUXGND B. UP Q841 Q842 RCA OUT Q171 IC171 NJM2360M 6,7 1 Q172 SL TUNPCE2 TUNPCE1 TUNPDI TUNPDO 97 65 66 68 69 TUNPCK 67 CE2 CE1 TUNPDO TUNPDI TUNPCK SL 12 1 VDD RESET IC961 S-80835CNMC-B8U RESET 2 Q912 ISENS Q971 AUXL AUXGND OEL POWER KEYD KEYAD CN621 3 2 1 KEY2 34 94 KEY1 WIRED REMOTE POWER CONNECTOR B.UP VIN CONTROL VOUT 13 14 6 2 5 12 10 9 23 Lch AUX CONNECTOR ROTARY COMMANDER S1811 ILLUMI D1803-D1813 13 CN1801 CN1802 IC1801 GP1UXC14RK REMOTE CONTROL SENSOR XCS CLKIN XCMD VDD5 VHA VHK SIN SCLI 14 6 2 DSENS OEL+B OEL UNIT 5 12 2 1 10 1 2 Phase-A Phase-B 19 9 18 10 91 89 88 87 90 95 27 100 3 1 17 1 2 11 14 20 15 7 16 3 12 13 9 ADKEY0 ROT0 DPDT KYDT REM RESET VCC VREF ROT1 SYSTEM CONTROLLER IC1802 PEG412A OEL DRIVER IC1803 PML019A CN1803 AUXL AUXG AUXL AUXG DPDT KYDT SWVDD ILM+ KEYBOARD UNIT B SWVDD 4 6 ADKEY1 ADKEY2 DCLK DOUT XRESET MCLK XCMD XOUT X1801 10.000MHz XIN KEY MATRIX S1803 BAND S1802 S1801 RDM SRC S1804 DISP S1805 S.Rtrv S1808 LIST S1807 S1806 EJECT CLOCK S1809 SW/BASS S1810 RPT Q1802 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-P410UB/XS/UC 22 1 2 3 4 1 2 3 4 C D F A B E 5. DIAGNOSIS 5.1 OPERATIONAL FLOWCHART SWVDD Vcc = 5 V Pin 16 Power ON BSENS = L DSENS = L BSENS Pin 18 ASENS Pin 75 ASENS = L DSENS Pin 19 H Pin 49 Source keys operative Completes power-on operation.(After that, proceed to each source operation.) SYSPW H Pin 48 ASENBO H Pin 40 Starts communication with Grille microcomputer. Source ON 300 ms 300 ms In case of the above signal, the communication with Grille microcomputer may fail. If the time interval is not 300 msec, the oscillator may be defective. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-P410UB/XS/UC 23 5 6 7 8 5 6 7 8 C D F A B E 5.2 ERROR CODE LIST - Error Messages If a CD is not operative or stopped during operation due to an error, the error mode is turned on and cause(s) of the error is indicated with a corresponding number. This arrangement is intended at reducing nonsense calls from the users and also for facilitating trouble analysis and repair work in servicing. (1) Basic Indication Method 1) When SERRORM is selected for the CSMOD (CD mode area for the system), error codes are written to DMIN (minutes display area) and DSEC (seconds display area). The same data is written to DMIN and DSEC. DTNO remains in blank as before. 2) Head unit display examples Depending on display capability of LCD used, display will vary as shown below. xx contains the error number. 8-digit display 6-digit display 4-digit display ERROR-xx ERR-xx E-xx (2) Error Code List Code Class Displayed error code Description of the code and potential cause(s) 10 Electricity Carriage Home NG CRG can't be moved to inner diameter. SERVO LSI Com- CRG can't be moved from inner diameter. munication Error -> Failure on home switch or CRG move mechanism. Communication error between microcomputer and SERVO LSI. 11 Electricity Focus Servo NG Focusing not available. -> Stains on rear side of disc or excessive vibrations on REWRITABLE. 12 Electricity Spindle Lock NG Spindle not locked. Sub-code is strange (not readable). Subcode NG -> Failure on spindle, stains or damages on disc, or excessive vibrations. A disc not containing CD-R data is found. Turned over disc are found, though rarely. CD signal error. 17 Electricity Setup NG AGC protection doesn't work. Focus can be easily lost. -> Damages or stains on disc, or excessive vibrations on REWRITABLE. 30 Electricity Search Time Out Failed to reach target address. -> CRG tracking error or damages on disc. 44 Electricity ALL Skip Skip setting for all track. (CD-R/RW) 50 Mechanism CD On Mech Error Mechanical error during CD ON. -> Defective loading motor, mechanical lock and mechanical sensor. A0 System Power Supply NG Power (VD) is ground faulted. -> Failure on SW transistor or power supply (failure on connector). Remarks: Mechanical errors are not displayed (because a CD is turned off in these errors). Unreadable TOC does not constitute an error. An intended operation continues in this case. Upper digits of an error code are subdivided as shown below: 1x: Setup relevant errors, 3x: Search relevant errors, Ax: Other errors. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-P410UB/XS/UC 24 1 2 3 4 1 2 3 4 C D F A B E iPod error Action Cause Message Transfer the songs to the iPod. No songs in the iPod NO SONGS STOP Disconnect the cable from the iPod. Once the iPod main menu is displayed, connect the cable again. Reset the iPod. ERROR-21 Reset the iPod. iPod failure ERROR-30 ERROR-A0 Check if the connection cable for the iPod shorted out. After checking, switch the ignition key or disconnect the iPod and connect again. USB error No songs in the USB device USB memory with security enabled is connected Follow the USB memory instructions to disable the security. TRK SKIPPED The connected USB device contains WMA files that are protected by DRM Play an audio file not protected by DRM. PROTECT All the files in the USB device are protected by DRM Transfer the songs not protected by DRM to the USB device. N/A USB The connected USB device is not supported by this unit Connect a USB device that is compliant as a Mass Storage Class. The USB connector or the USB cable is short-circuited Confirm the USB connector or the USB cable. The connected USB device consumes more than 500 mA (max. allowable current) Confirm the USB device. Selected m3u playlist cannot be played back All the files on the selected m3u playlist are protected by DRM Select another playlist. N/A PLAYLIST ERROR-11 NO AUDIO CHK USB No songs in the current list Select a list that contains the songs. Communication failure Old version of the iPod Update the iPod version. iPod is not charged but operates correctly. Action Cause Message Transfer the songs to the USB device. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-P410UB/XS/UC 25 5 6 7 8 5 6 7 8 C D F A B E 5.3 CONNECTOR FUNCTION DESCRIPTION POWER SUPPLY 1. FR+ 2. RR+ 3. FR- 4. RR- 5. FL+ 6. RL+ 7. FL- 8. RL- IP-BUS 1. BUS+ 2. GND 3. GND 4. NC 5. BUS- 6. GND 7. Lch 8. ASEN 9. Rch 10. Rch-GND 11. Lch-GND 1 3 5 7 9 11 13 15 2 4 6 8 10 12 14 16 1 2 3 4 5 6 7 8 9 10 11 9. NC 10. NC 11. B.REM 12. ILM 13. NC 14. ACC 15. GND 16. B.UP 1. VBUS 2. D- 3. D+ 4. GND USB ANTENNA WIRED REMOTE INPUT USB REAR OUTPUT FRONT OUTPUT SUBWOOFER OUTPUT 1 2 3 4 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-P410UB/XS/UC 26 1 2 3 4 1 2 3 4 C D F A B E 6. SERVICE MODE 6.1 DISPLAY TEST MODE 1. To enter the test mode Turn on ACC and Backup while pressing the RPT button and the DISP button together. 2. To exit from the test mode Turn off ACC and Backup 3. Operation method Change display as follows by pressing the RPT button and the DISP button together. Normal display --> Display stop --> All light of display --> .... www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-P410UB/XS/UC 27 5 6 7 8 5 6 7 8 C D F A B E 6.2 CD TEST MODE • How to issue the 1 - 6 keys in the 08 model's slave test: The specification of the 08 model does not include the 1 - 6 keys issuance function for H/U and the remote control unit. Therefore, in order to issue commands in a slave test, use the direct FUNCTION keys alternatively to enable the equal key command sending function to the existing models. Outline) Use the direct FUNCTION keys to display, select, or issue the KEY 1 - 6. • For convenience, a name of each direct FUNCTION key is shown as "A", "B", and "C". • How to issue the 1 - 6 keys for the CDS source: (The areas below are overwritten and displayed on character strings for the normal mode display.) 1 During the slave test mode, the key name "K1" is shown at the left by default. In this condition, press the A key to toggle K1 - K6, and select a command to be sent to the slave. C O M P A C T D I S C K 1 ! T - ! ! ! ! ! ! • The one-line model shows only the bottom column. D N O C E S E T U N I M K R T R E D L O F C O M P A C T D I S C K 6 T 2 During the K1 - K6 key names are displayed, press the B key and issue the selected command. C O M P A C T D I S C Send a key command selected by K 1 T pressing the KEY 1. B key 3 Press the C key to change display/non-display of key names. When the non-display mode is selected for the K1 - K6 key names, "A key" and "B key" are invalid. C O M P A C T D I S C K 1 T C key C O M P A C T D I S C F - ! T • Pressing the A key or B key does not work. RDM/SHFL/FUNC2 Issuing a key command C Switching a screen B Direct FUNCTION key Normal mode Slave test mode A Selecting a key command RPT/LOCAL/FUNC3 S.Rtrv/FUNC1 ! - ! ! ! ! ! ! ! - ! ! ! ! ! ! ! - ! ! ! ! ! ! ! - ! ! ! ! ! ! A key www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-P410UB/XS/UC 28 1 2 3 4 1 2 3 4 C D F A B E [Key] Contents Display [SRC] + [RPT] + Reset or [SRC] + [RPT] + BU + ACC Test Mode In [CD] or [SRC] Source On TRK MIN SEC [BAND] Power On (T.Offset is adjusted) TRK MIN SEC 00 00 00 [3] Power On (T.Offset is not adjusted) 99 99 99 [2] RF AMP Gain switching GG GG GG *1 [4] SPINDLE Speed switching SP SP SP *9 [3] Focus Close S curve check TRK MIN SEC 91 91 91 [6] Focus Mode switching 0X 0X 0X *2 [1] Tracking Servo Close 00 00 00 or 99 99 99 [>] CRG + [2] Self-adjusting switching TRK MIN SEC ?? ?? ?? *3 *8 [<] CRG - *8 [BAND] Power Off TRK MIN SEC [BAND] Power Off TRK MIN SEC [BAND] Power Off TRK MIN SEC [BAND] Power Off TRK MIN SEC [1] T.Close & AGC Applicable servomechanism TRK MIN SEC ?tr ?min ?sec [6] [3] RF AGC / RF AGC coefficient display [>] CRG + 8X 8X 8X or 9X 9X 9X [2] T.Balance adjustment / T.BAL coefficient display TRK MIN SEC ?? ?? ?? [<] CRG - T.Close Applicable servomechanism ?? ?? ?? [1] F,T,RF AGC F.Bias display switching TRK MIN SEC TRK MIN SEC TRK MIN SEC TRK MIN SEC ?tr ?min ?sec TRK MIN SEC [3] [6] CRG/TR jump value switching [>] CRG/TR Jump + [2] Tracking Open [<] CRG/TR Jump - ?tr ?min ?sec TRK MIN SEC TRK MIN SEC TRK MIN SEC ?tr ?min ?sec 00 00 00 or 99 99 99 TRK MIN SEC TRK MIN SEC ?tr ?min ?sec 8X 8X 8X or 9X 9X 9X 8X 8X 8X or 9X 9X 9X 00 00 00 or 99 99 99 TRK MIN SEC ?tr ?min ?sec ?? ?? ?? *7 F,T AGC / F.Bias RF AGC 8X 8X 8X or 9X 9X 9X [2] Tracking Open *6 *5 *4 *4 Operation [Key] Test Mode [BAND] Power On/Off [>] CRG + / TR Jump + (Direction of the external surface) [<] CRG - / TR Jump - (Direction of the internal surface) [1] T. CLS & AGC & Applicable servomechanism / AGC,AGC display setting [2] RF Gain switching / Offset adjustment display / T.Balance adjustment / T. Open [3] F. Close,S Curve / Rough Servo and RF AGC / F,T,RF AGC [4] SPDL 1X/2X switching As for the double speed(2x), audio output cannot be supported. [5] Error Rate measurement ON : ERR 30 Counts Start BER display data[%] [6] F. Mode switching / Tracking Close / CRG•TR Jump Switching • As for the double speed (2x), audio output cannot be supported • After the [Eject] key is pressed keys other than the [Eject] key should not be pressed, until disc ejection is complete. • When the key [2] or [3] is pressed during the Focus Search, the power supply should be immediately turned off (otherwise the lens sticks to Wall, causing the actuator to be damaged). • In the case of TR jump other than to 100TR, the function shall continue to be processed even if the TR jump key is released. As for the CRG Move and 100TR Jump, the mechanism shall be set to the Tracking Close mode when the key is released. • When the power is turned on/off the jump mode is reset to the Single TR (91) while the gain of the RFAMP is reset to 0 dB. At the same time all the self-adjusting values shall return to the default setting. *10 TRK MIN SEC [5] Gop Mode Gop Mode switching OL OL OL - Flow Chart *1) TYP -> + 6 dB -> + 12 dB TRK MIN SEC TRK06MIN06SEC06 TRK12MIN12SEC12 *2) Focus Close -> S.Curve -> F EQ measurement setting TRK00MIN00SEC00 TRK01MIN01SEC01 TRK02MIN02SEC02 (TRK99MIN99SEC99) *3) F.Offset Display -> RF.Offset -> T.Offset Display -> Switch to the order of the original display *4) 1TR/4TR/10TR/32TR/100TR *5) Single -> 4TR -> 10TR -> 32TR -> 100TR -> CRG Move 9x(8x):91(81) 92(82) 93(83) 94(84) 95(85) 96(86) *6) Only at the time of CRG move, 100TR jump *7) TRK/MIN/SEC -> F.AGC -> T.AGC Gain -> F Bias -> RF AGC *8) CRG motor voltage = 2 [V] *9) TYP (1X) -> 2X -> 1X TRK MIN SEC TRK22MIN22SEC22 TRK11MIN11SEC11 *10) OFF(TYP) -> FORCUS -> TRACKING TRK MIN SEC TRK70MIN70SEC70 TRK71MIN71SEC71 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-P410UB/XS/UC 29 5 6 7 8 5 6 7 8 C D F A B E 7. DISASSEMBLY 2 1 2 3 Fig.1 Fig.2 - Removing the CD Mechanism Module (Fig.1) CD Mechanism Module - Removing the Tuner Amp Unit (Fig.2) 1. Remove the Case. Remove the three screws. Remove the screw. Straighten the tabs at four locations indicated and then remove the Tuner Amp Unit. 1 2 1 1 2 2 Disconnect the connector and then remove the CD Mechanism Module. Tuner Amp Unit 1 Release the three latches and then remove the Panel Assy. Remove the four screws. - Removing the Case (not shown) Panel Assy 1 3 3 2 2 3 3 1 1 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-P410UB/XS/UC 30 1 2 3 4 1 2 3 4 C D F A B E A A B B B B B a B Upper Frame Lower Frame Damper Carriage Mechanism Damper Do not squeeze this area. - How to hold the Mechanism Unit - Removing the Upper and Lower Frames 1. With a disc inserted and clamped in the mechanism, remove the two Springs (A), the six Springs (B), and the four Screws. 2. Turn the Upper Frame using the part "a" as a pivot, and remove the Upper Frame. 3. While lifting the Carriage Mechanism, remove it from the three Dampers. Caution: When assembling, be sure to apply some alcohol to the Dampers and assemble the mechanism in a clamped state. 1. Hold the Upper and Lower Frames. 2. Do not hold the front portion of the Upper Frame, because it is not very solid. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-P410UB/XS/UC 31 5 6 7 8 5 6 7 8 C D F A B E Screw Shorting Solder CD Core Unit Solder - How to remove the CD Core Unit 1. Apply Shorting Solder to the flexible cable of the Pickup, and disconnect it from the connector. 2. Unsolder the four leads, and loosen the Screw. 3. Remove the CD Core Unit. Caution: When assembling the CD Core Unit, assemble it with the SW in a clamped state so as not to damage it. Chassis Pickup Rack Pickup Poly Washer Change Arm Pickup Lock Arm Feed Screw Inner Holder Planet Gear - How to remove the Pickup Unit 1. Make the system in the carriage mechanism mode, and have it clamped. 2. Remove the CD Core Unit and remove the leads from the Inner Holder. 3. Remove the Poly Washer, Change Arm, and Pickup Lock Arm. 4. While releasing from the hook of the Inner Holder, lift the end of the Feed Screw. Caution: When assembling, move the Planet Gear to the load/eject position before setting the Feed Screw in the Inner Holder. Assemble the sub unit side of the Pickup, taking the plate (Chassis) in-between. When treating the leads of the Load Carriage Motor Assy, do not make them loose over the Feed Screw. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-P410UB/XS/UC 32 1 2 3 4 1 2 3 4 C D F A B E 8. EACH SETTING AND ADJUSTMENT 8.1 CD ADJUSTMENT 1) Cautions on adjustments In this product the single voltage (3.3 V) is used for the regulator. The reference voltage is the REFO1 (1.65 V) instead of the GND. If you should mistakenly short the REFO1 with the GND during adjustment, accurate voltage will not be obtained, and the servo’s misoperation will apply excessive shock to the pickup. To avoid such problems: a. Do not mix up the REFO1 with the GND when connecting the (-) probe of measuring instruments. Especially on an oscilloscope, avoid connecting the (-) probe for CH1 to the GND. b. In many cases, measuring instruments have the same potential as that for the (-) probe. Be sure to set the measuring instruments to the floating state. c. If you have mistakenly connected the REFO1 to the GND, turn off the regulator or the power immediately. Before mounting and removing filters or leads for adjustment, be sure to turn off the regulator. For stable circuit operation, keep the mechanism operating for about one minute or more after the regulator is turned on. In the test mode, any software protections will not work. Avoid applying any mechanical or electrical shock to the mechanism during adjustment. The RFI and RFO signals with a wide frequency range are easy to oscillate. When observing the signals, insert a resistor of 1k ohms in series. The load and eject operation is not guarantied with the mechanism upside down. If the mechanism is blocked due to mistaken eject operation, reset the product or turn off and on the ACC to restore it. 2) Test mode This mode is used to adjust the CD mechanism module. To enter the test mode. While pressing the 4 and 6 keys at the same time, reset. To exit from the test mode. Turn off the ACC and back up. Notes: a. During ejection, do not press any other keys than the EJECT key until the loaded disc is ejected. b. If you have pressed the (->) key or (<-) key during focus search, turn off the power immediately to protect the actuator from damage caused by the lens stuck. c. For the TR jump modes except 100TR, the track jump operation will continue even if the key is released. d. For the CRG move and 100TR jump modes, the tracking loop will be closed at the same time when the key is released. e. When the power is turned off and on, the jump mode is reset to the single TR (91), the RF amp gain is set to 0 dB, and the auto-adjustment values are reset to the default settings. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-P410UB/XS/UC 33 5 6 7 8 5 6 7 8 C D F A B E 8.2 CHECKING THE GRATING AFTER CHANGING THE PICKUP UNIT CD CORE UNIT Note : The grating angle of the PU unit cannot be adjusted after the PU unit is changed. The PU unit in the CD mechanism module is adjusted on the production line to match the CD mechanism module and is thus the best adjusted PU unit for the CD mechanism module. Changing the PU unit is thus best considered as a last resort. However, if the PU unit must be changed, the grating should be checked using the procedure below. Purpose : To check that the grating is within an acceptable range when the PU unit is changed. Symptoms of Mal-adjustment : If the grating is off by a large amount symptoms such as being unable to close tracking, being unable to perform track search operations, or taking a long time for track searching. Method : Measuring Equipment Measuring Points Oscilloscope, Two L.P.F. E, F, REFO1 Disc TCD-782 Mode TEST MODE Checking Procedure 1. In test mode, load the disc and switch the 3 V regulator on. 2. Using the -> and <- buttons, move the PU unit to the innermost track. 3. Press key 3 to close focus, the display should read "91". Press key 2 to implement the tracking balance adjustment the display should now read "81". Press key 3. The display will change, returning to "81" on the fourth press. 4. As shown in the diagram above, monitor the LPF outputs using the oscilloscope and check that the phase difference is within 75 degrees. Refer to the photographs supplied to determine the phase angle. 5. If the phase difference is determined to be greater than 75 degrees try changing the PU unit to see if there is any improvement. If, after trying this a number of times, the grating angle does not become less than 75 degrees then the mechanism should be judged to be at fault. Note Because of eccentricity in the disc and a slight misalignment of the clamping center the grating waveform may be seen to "wobble" ( the phase difference changes as the disc rotates). The angle specified above indicates the average angle. Hint Reloading the disc changes the clamp position and may decrease the "wobble". 100 kohm 390 pF 100 kohm 390 pF E VREF F VREF Xch Ych L.P.F. L.P.F. Oscilloscope F E REFO1 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-P410UB/XS/UC 34 1 2 3 4 1 2 3 4 C D F A B E Grating waveform 45 degrees 0 degrees 75 degrees 60 degrees 30 degrees 90 degrees Ech -> Xch 20 mV/div, AC Fch -> Ych 20 mV/div, AC www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-P410UB/XS/UC 35 5 6 7 8 5 6 7 8 C D F A B E 8.3 PCL OUTPUT CONFIRMATION - PCL Output In the normal operation mode (with the detachable panel installed, the ACC switched ON, the standby mode cancelled), shift the TESTIN IC601(Pin 63) terminal to H. The clock signal is output from the PCL terminal IC601(Pin 39). The frequency of the clock signal is 468 750 Hz that is one 32th of the fundamental frequency. The clock signal should be 468 750 Hz (- 10 Hz, + 15 Hz) If the clock signal out of the range, the X’tal (X601) should be replaced with new one. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-P410UB/XS/UC 36 1 2 3 4 1 2 3 4 C D F A B E 9. EXPLODED VIEWS AND PARTS LIST 9.1 PACKING NOTES : Parts marked by " * " are generally unavailable because they are not in our Master Spare Parts List. The > mark found on some component parts indicates the importance of the safety factor of the part. Therefore, when replacing, be sure to use parts of identical designation. Screw adjacent to mark on the product are used for disassembly. For the applying amount of lubricants or glue, follow the instructions in this manual. (In the case of no amount instructions,apply as you think it appropriate.) " DEH-P4150UB/XS/ES DEH-P4150UB/XS/ES DEH-P4150UB/XS/ES DEH-P4150UB/XS/ES DEH-P410UB/XS/UC DEH-P4100UB/XS/UC DEH-P410UB/XS/UC DEH-P4100UB/XS/UC www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-P410UB/XS/UC 37 5 6 7 8 5 6 7 8 C D F A B E (1) PACKING SECTION PARTS LIST (2) CONTRAST TABLE DEH-P410UB/XS/UC, DEH-P4100UB/XS/UC and DEH-P4150UB/XS/ES are constructed the same except for the following: Owner's Manual,Installation Manual Mark No. Description Part No. 1 Cord Assy See Contrast table (2) 2 Polyethylene Bag See Contrast table (2) * 3 Battery CEX1065 4 Remote Control Assy CXC8885 5 Cord Assy YDP5030 6 Cord Assy See Contrast table (2) 7 Accessory Assy See Contrast table (2) 8 Screw See Contrast table (2) 9 Screw Assy See Contrast table (2) 10 Screw See Contrast table (2) * 11 Polyethylene Bag CEG-127 12 Screw CRZ50P090FTC 13 Screw TRZ50P080FTC 14 Polyethylene Bag CEG1160 15 Handle CND3707 16 Bush See Contrast table (2) 17 Unit Box See Contrast table (2) 18 Contain Box See Contrast table (2) 19 Protector See Contrast table (2) 20 Protector See Contrast table (2) 21-1 Caution Card CRP1387 * 21-2 Warranty Card See Contrast table (2) 21-3 Installation Manual See Contrast table (2) 21-4 Owner's Manual See Contrast table (2) 21-5 Caution Card See Contrast table (2) 22 Case Assy See Contrast table (2) Mark No. Description Part No. Mark No. Description DEH-P410UB/XS/UC DEH-P4100UB/XS/UC DEH-P4150UB/XS/ES 1 Cord Assy CDP1220 Not used Not used 2 Polyethylene Bag CEG1173 CEG1173 CEG-162 6 Cord Assy YDP5024 YDP5024 YDP5018 7 Accessory Assy *YEA5071 *YEA5071 CEA9954 8 Screw BPZ20P060FTC BPZ20P060FTC Not used 9 Screw Assy YEA5072 YEA5072 CEA3849 10 Screw Not used Not used CBA1650 16 Bush Not used Not used CNV3930 17 Unit Box YHG5484 YHG5483 YHG5485 18 Contain Box YHL5484 YHL5483 YHL5485 19 Protector YHP5052 YHP5052 YHP5050 20 Protector YHP5053 YHP5053 YHP5051 * 21-2 Warranty Card CRY1280 CRY1276 Not used 21-3 Installation Manual YRD5263 YRD5262 YRD5264 21-4 Owner's Manual YRD5266 YRD5265 YRD5267 21-5 Caution Card Not used CRP1386 Not used 22 Case Assy Not used Not used YXB5009 Part No. Language YRD5262 English, French, Spanish(Espanol) YRD5263 English, French, Spanish(Espanol) YRD5264 English, Arabic YRD5265 English, French, Spanish(Espanol) YRD5266 English, French, Spanish(Espanol) YRD5267 English, Arabic www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-P410UB/XS/UC 38 1 2 3 4 1 2 3 4 C D F A B E 9.2 EXTERIOR (1) A A A DEH-P4100UB/XS/UC www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-P410UB/XS/UC 39 5 6 7 8 5 6 7 8 C D F A B E (1) EXTERIOR (1) SECTION PARTS LIST (2) CONTRAST TABLE DEH-P410UB/XS/UC, DEH-P4100UB/XS/UC and DEH-P4150UB/XS/ES are constructed the same except for the following: Mark No. Description Part No. 1 Screw BSZ26P060FTC 2 Screw BSZ30P060FTC 3 Screw BSZ30P200FTC 4 Earth Plate CNC8915 5 Cushion CNM8890 6 CD Mechanism Module(S10.5) CXK5774 7 Cable YDE5030 8 Cord Assy YDE5047 9 Tuner Amp Assy See Contrast table (2) 10 Screw BPZ26P080FTC 11 Screw BSZ26P060FTC 12 Screw BSZ26P200FTC 13 Clamper CEF1050 14 Plug(CN901) CKM1376 15 Connector(CN101) CKS3408 16 Connector(CN701) CKS3833 17 Connector(CN803) CKS5664 18 Antenna Jack(CN401) CKX1070 19 FM/AM Tuner Unit(Y401) CWE2098 20 Holder CND4324 21 Plug(CN251) KM200NA5L 22 Holder QNC3001 23 Pin Jack(CN351) XKB7001 24 Holder XNC7030 > 25 Fuse(10 A) YEK5001 26 Jack(CN621) YKS5002 27 Heat Sink YNR5128 28 Chassis Unit YXA5634 29 Button CAC4836 30 Spring CBH2367 31 SpringÅiSilver) CBH2961 32 SpringÅiBlack) CBH2962 33 Arm CNV9311 34 Arm CNV9312 35 Cover YNN5016 36 Panel YNS5480 37 Screw See Contrast table (2) 38 Holder See Contrast table (2) 39 IC(IC301) PAL007C 40 IC(IC921) NJM2388F84 41 Transistor(Q702, Q911) 2SD2396 Mark No. Description Part No. Mark No. Description DEH-P410UB/XS/UC DEH-P4100UB/XS/UC DEH-P4150UB/XS/ES 9 Tuner Amp Assy YWM5394 YWM5392 YWM5396 37 Screw Not used BMZ40P140FTC Not used 38 Holder Not used CNV7619 Not used www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-P410UB/XS/UC 40 1 2 3 4 1 2 3 4 C D F A B E 9.3 EXTERIOR (2) A A B www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-P410UB/XS/UC 41 5 6 7 8 5 6 7 8 C D F A B E (1) EXTERIOR (2) SECTION PARTS LIST (2) CONTRAST TABLE DEH-P410UB/XS/UC, DEH-P4100UB/XS/UC and DEH-P4150UB/XS/ES are constructed the same except for the following: Mark No. Description Part No. 1 Holder CND3598 2 Remote Control Assy CXC8885 3 Cover CNS7068 4 Cord Assy See Contrast table (2) 5 Case YNB5014 6 Panel YNS5517 7 Detach Assy See Contrast table (2) 8 Screw BPZ20P100FTB 9 Spring CBH2210 10 Button(DETACH) YAC5366 11 Button(EJECT) YAC5367 12 Button(CLOCK) YAC5368 13 Cover YNS5459 14 Holder YNV5180 15 Connector(CN1801) CKS5663 16 Connector(CN1803) CKS5865 17 OLED MXS8250 18 Jack(CN1802) YKN5006 19 Holder YNC5063 20 Cushion YNM5029 21 Holder Unit YXA5566 22 Grille Unit See Contrast table (2) 23 Button Unit(S.Rtrv, SW, iPod, LOC) See Contrast table (2) 24 Knob Unit See Contrast table (2) 25 Spring YBL5013 26 Button Unit(SRC, BAND) YXA5567 27 Button Unit(LIST, DISP) YXA5568 28 Remote IC(IC1801) GP1UXC14RK Mark No. Description Part No. Mark No. Description DEH-P410UB/XS/UC DEH-P4100UB/XS/UC DEH-P4150UB/XS/ES 4 Cord Assy YDP5024 YDP5024 YDP5018 7 Detach Assy YXA5581 YXA5580 YXA5583 22 Grille Unit YXA5519 YXA5518 YXA5520 23 Button Unit YXA5521 YXA5521 YXA5570 24 Knob Unit YXA5522 YXA5523 YXA5523 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-P410UB/XS/UC 42 1 2 3 4 1 2 3 4 C D F A B E 9.4 CD MECHANISM MODULE B C A B C D E 5 19 A 19 5 5 5 19 19 27 48 29 13 13 66 44 44 72 8 15 60 46 33 62 38 39 40 28 4 47 17 37 14 12 35 6 45 52 53 65 64 18 32 41 5 61 49 8 51 55 51 56 59 43 10 20 57 16 25 58 31 23 69 71 70 70 63 73 21 7 19 24 19 24 67 4 36 68 50 (1) (1) (1) (1) (1) (1) (1) E 30 34 22 42 11 26 (1) (1) (1) (1) (1) (1) (1) (1) (1) (1) (1) (2) (2) (2) (1) (1) (2) (1) (2) (1) (1): GEM1024 : GEM1045 (2) (2) 1 2 3 74 D C 54 9 9 (1) (2) (2) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-P410UB/XS/UC 43 5 6 7 8 5 6 7 8 C D F A B E CD MECHANISM MODULE SECTION PARTS LIST Mark No. Description Part No. 1 CD Core Unit(S10.5 iPod-Code2 Class4) CWX3712 2 Connector(CN101) CKS4911 3 Connector(CN701) CKS4915 4 Screw BMZ20P025FTC 5 Screw BSZ20P040FTC 6 Screw(M2 x 3) CBA1511 7 Screw(M2 x 4) CBA1835 8 Washer CBF1038 9 Roller CNV9499 10 Spring CBH2609 11 Spring CBH2612 12 Spring CBH2614 13 Spring CBH2616 14 Spring CBH2617 15 Spring CBH2620 16 Spring CBH2855 17 Spring CBH2937 18 Spring CBH2735 19 Spring CBH2854 20 Spring CBH2642 21 Spring CBH2856 22 Spring CBH2857 23 Spring CBH2860 24 Spring CBH2861 25 Spring CBL1686 26 Arm CND1909 27 Frame CND2582 28 Bracket CND2583 29 Arm CND3831 30 Lever CND2585 31 Arm CND2586 32 Bracket CND2587 33 Arm CND2588 34 Lever CND2589 35 Holder CNV9522 36 Gear CNV7207 37 Gear CNV9513 38 Gear CNV7209 39 Gear CNV9514 40 Gear CNV9515 41 Gear CNV9516 42 Rack CNV9517 43 Arm CNV7216 44 Roller CNV8189 45 Gear CNV9518 46 Guide CNV9519 47 Gear CNV7595 48 Guide CNV9520 49 Arm CNV7805 50 Rack CNV8342 51 Roller CNV8343 52 Holder CNV8344 53 Arm CNV8345 54 Guide CNV9498 55 Arm CNV8348 56 Arm CNV8349 57 Arm CNV8350 58 Clamper CNV8365 59 Arm CNV8386 60 Guide CNV8396 61 Arm CNV9521 62 Collar CNV8447 63 Motor Unit(M2) CXC4026 64 Arm Unit CXC4027 65 Chassis Unit CXC4028 66 Gear Unit CXC4029 67 Frame Unit CXC4031 68 Motor Unit(M1) CXC7134 69 Screw Unit CXC6359 70 Screw JFZ20P025FTC 71 Screw JGZ17P022FTC 72 Washer YE20FTC 73 Pickup Unit(P10.5)(Service) CXX1942 74 Screw IMS26P030FTC Mark No. Description Part No. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-P410UB/XS/UC 44 1 2 3 4 1 2 3 4 C D F A B E 10. SCHEMATIC DIAGRAM 10.1 TUNER AMP ASSY(GUIDE PAGE) A A-a A-a A-b A-a A-b A-b A-a Large size SCH diagram Guide page Detailed page Note: When ordering service parts, be sure to refer to " EXPLODED VIEWS AND PARTS LIST" or "ELECTRICAL PARTS LIST". PEG407B B CN1801 CN701 FM/AM TUNER UNIT IP-BUS USB For resistors and capacitors in the circuit diagrams, their resistance values or capacitance values are expressed in codes: Ex. *Resistors Code Practical value 123 12k ohms 103 10k ohms *Capacitors Code Practical value 103 0.01uF 101/10 100uF/10V The > mark found on some component parts indicates the importance of the safety factor of the part. Therefore, when replacing, be sure to use parts of identical designation. Symbol indicates a resistor. No differentiation is made between chip resistors and discrete resistors. NOTE : Symbol indicates a capacitor. No differentiation is made between chip capacitors and discrete capacitors. C www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-P410UB/XS/UC 45 5 6 7 8 5 6 7 8 C D F A B E A A-b DEH-P410UB/XS/UC DEH-P4100UB/XS/UC DEH-P4150UB/XS/ES 600uH 3A NJM2360M A TUNER AMP ASSY es > B.UP GND RL- RL+ FL- FL+ B.REM ILM ACC RR- RR+ FR- FR+ www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-P410UB/XS/UC 46 1 2 3 4 1 2 3 4 C D F A B E A-a A-b A-b DEH-P410UB/XS/UC DEH-P4100UB/XS/UC DEH-P4150UB/XS/ES 600uH 3A A TUNER AMP ASSY > B.UP GND ACC www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-P410UB/XS/UC 47 5 6 7 8 5 6 7 8 C D F A B E A-a A-b A-b 600uH NJM2360M B.UP GND RL- RL+ FL- FL+ B.REM ILM ACC RR- RR+ FR- FR+ www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-P410UB/XS/UC 48 1 2 3 4 1 2 3 4 C D F A B E A-b A-a A-a A-b DEH-P4 DEH-P4 DEH-P41 PEG407B CN701 FM/AM TUNER UNIT IP-BUS USB C www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-P410UB/XS/UC 49 5 6 7 8 5 6 7 8 C D F A B E A-a A-b A-b A-a B CN1801 USB For resistors and capacitors in the circuit diagrams, their resistance values or capacitance values are expressed in codes: Ex. *Resistors Code Practical value 123 12k ohms 103 10k ohms *Capacitors Code Practical value 103 0.01uF 101/10 100uF/10V The > mark found on some component parts indicates the importance of the safety factor of the part. Therefore, when replacing, be sure to use parts of identical designation. Symbol indicates a resistor. No differentiation is made between chip resistors and discrete resistors. NOTE : Symbol indicates a capacitor. No differentiation is made between chip capacitors and discrete capacitors. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-P410UB/XS/UC 50 1 2 3 4 1 2 3 4 C D F A B E 10.2 KEYBOARD UNIT B A CN803 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-P410UB/XS/UC 51 5 6 7 8 5 6 7 8 C D F A B E B B KEYBOARD UNIT OEL UNIT MXS8250 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-P410UB/XS/UC 52 1 2 3 4 1 2 3 4 C D F A B E 10.3 CD MECHANISM MODULE(GUIDE PAGE) C-a C PICKUP UNIT(P10.5)(SERVICE) M1 CXC7134 SPINDLE MOTOR M2 CXC4026 LOADING/CARRIAGE MOTOR SWITCHES: CD CORE UNIT(S10.5COMP2-iPod-C2) S901:HOME SWITCH.........ON-OFF S903:DSCSNS SWITCH.....ON-OFF S904:12EJ SWITCH............ON-OFF S905:8EJ SWITCH..............ON-OFF The underlined indicates the switch position. ACTUATOR/ MOTOR DRIVER F T F T F F T T T F T C S S C T F F F T T S S C C S S C C F T F T 1 2 3 4 5 7 8 9 a c d e f P www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-P410UB/XS/UC 53 5 6 7 8 5 6 7 8 C D F A B E C-b C C CD CORE UNIT(S10.5 iPod-Code2 Class4) A CN701 iPod AUTHENTICATION COPROCESSOR F SIGNAL LINE FOCUS SERVO LINE TRACKING SERVO LINE CARRIAGE SERVO LINE SPINDLE SERVO LINE T C S 6 b g h i j m l k PE5675A 341S2162 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-P410UB/XS/UC 54 1 2 3 4 1 2 3 4 C D F A B E C-a C-b C-b 2 1 PE5675A C CD CORE UNIT(S10.5 iPod-Code2 Class4) F SIGNAL LINE FOCUS SERVO LINE TRACKING SERVO LINE CARRIAGE SERVO LINE SPINDLE SERVO LINE T C S b m www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-P410UB/XS/UC 55 5 6 7 8 5 6 7 8 C D F A B E C-a C-b C-b 341S2162 A CN701 iPod AUTHENTICATION COPROCESSOR 6 g h i j m l k www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-P410UB/XS/UC 56 1 2 3 4 1 2 3 4 C D F A B E C-b C-a C-a C-b 2 1 PICKUP UNIT(P10.5)(SERVICE) SWITCHES: CD CORE UNIT(S10.5COMP2-iPod-C2) S901:HOME SWITCH.........ON-OFF S903:DSCSNS SWITCH.....ON-OFF S904:12EJ SWITCH............ON-OFF S905:8EJ SWITCH..............ON-OFF F T F T F F T T T F T C S F T F T c d f www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-P410UB/XS/UC 57 5 6 7 8 5 6 7 8 C D F A B E C-a C-b C-b C-a M1 CXC7134 SPINDLE MOTOR M2 CXC4026 LOADING/CARRIAGE MOTOR SWITCHES: CD CORE UNIT(S10.5COMP2-iPod-C2) S901:HOME SWITCH.........ON-OFF S903:DSCSNS SWITCH.....ON-OFF S904:12EJ SWITCH............ON-OFF S905:8EJ SWITCH..............ON-OFF The underlined indicates the switch position. ACTUATOR/ MOTOR DRIVER S C T F F F T T S S C C S S C C 1 2 3 4 5 7 8 9 a e www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-P410UB/XS/UC 58 1 2 3 4 1 2 3 4 C D F A B E 10.4 WAVEFORMS - CD CORE UNIT Note : 1. The encircled numbers denote measuring points in the circuit diagram. 2. Reference voltage REFO1(1.65 V) 500 ms/div 5 V/div 5 V/div 5 V/div 10 V/div 1DSCSNS 5CLCONT 4LOEJ 6VD 5 V/div 5 V/div 5 V/div 5 V/div 1DSCSNS 28SNS 312SNS 4LOEJ 5 V/div 5 V/div 5 V/div 5 V/div 500 ms/div 1DSCSNS 28SNS 312SNS 4LOEJ 500 mV/div 500 mV/div 200 ms/div @TE #FE 200 mV/div 2 V/div 2 V/div 500 ms/div 0FIN !RFOK(MONI_3) 7SIN 1 V/div 500 mV/div 1 V/div 1 s/div 500 ms/div 7SIN 8CIN 9TIN 2 V/div 500 mV/div 5 µs/div $MDX 7SIN 2 V/div 500 mV/div 200 ms/div $MDX 7SIN 500 mV/div 500 mV/div 500 mV/div 500 mV/div 20 ms/div #FE 0FIN @TE 9TIN 1 V/div 500 mV/div 500 mV/div 500 µs/div %RFAGC @TE 9TIN 500 mV/div 500 mV/div 2 ms/div @TE %RFAGC 500 mV/div 500 mV/div 200 ms/div 0FIN #FE Source On setup operation 12 cm CD-DA Source On setup operation CD-DA Play operation Spindle waveform during play operation Spindle waveform during play operation (Wider) Focus Search waveform Track Open waveform 1 Track Jump waveform 12 cm CD-DA setup operation after loading 12 cm CD Loading operation 12 cm CD Loading operation 8 cm CD Loading operation Ref.: GND Mode: Normal Ref.: GND Mode: Normal Ref.: GND Mode: Normal Ref.: REFO Mode: Normal Ref.: REFO Mode: Normal Ref.: REFO Mode: Normal Ref.: REFO Mode: TEST Ref.: REFO Mode: TEST Ref.: REFO Mode: TEST Ref.: REFO Mode: Normal Ref.: REFO Mode: Normal Ref.: REFO Mode: Normal www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-P410UB/XS/UC 59 5 6 7 8 5 6 7 8 C D F A B E 1 V/div 500 mV/div 500 mV/div 2 ms/div %RFAGC @TE 9TIN 1 V/div 500 mV/div 500 mV/div 500 µs/div %RFAGC @TE 9TIN 1 V/div 500 mV/div 500 mV/div 500 µs/div %RFAGC @TE 9TIN 5 V/div 5 V/div 5 V/div 5 V/div 500 ms/div 1DSCSNS 28SNS 312SNS 4LOEJ 1 V/div 1 V/div 200 µs/div ^LOUT &ROUT 1 V/div 1 V/div 1 V/div 2 V/div 200 ms/div %RFAGC @TE 8CIN 7SIN 1 V/div 1 V/div 1 V/div 1 V/div 500 µs/div %RFAGC 9TIN @TE 0FIN 5 V/div 5 V/div 5 V/div 5 V/div 500 ms/div 1DSCSNS 28SNS 312SNS 4LOEJ 5 V/div 5 V/div 5 V/div 500 ms/div 1DSCSNS 5CLCONT 4LOEJ 12 cm CD Eject operation Analog audio waveform 12 cm CD Eject operation 8 cm CD Eject operation Black dot(800 µm) during play Search operation(Outter to Inner) 4 Tracks Jump waveform 10 Tracks Jump waveform 32 Tracks Jump waveform Ref.: REFO Mode: TEST Ref.: REFO Mode: TEST Ref.: REFO Mode: TEST Ref.: GND Mode: Normal Ref.: REFO Mode: Normal Ref.: GND Mode: Normal 2 V/div 2 V/div 50 ms/div *DP (DM 2 V/div 2 V/div 50 ms/div *DP (DM 1 V/div 1 V/div 50 ns/div *DP (DM USB Play USB device inserting to USB connector. CD Play with USB(iPod) device connecting. Ref.: REFO Mode: Normal Ref.: GND Mode: Normal Ref.: AGND Mode: Normal www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-P410UB/XS/UC 60 1 2 3 4 1 2 3 4 C D F A B E 2 V/div 2 V/div 2 V/div 500 ms/div )CPRST ⁄SDA ¤SCL 2 V/div 2 V/div 50 ms/div *DP (DM ACC OFF with USB(iPod) device connecting. iPod Authentication Operation www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-P410UB/XS/UC 61 5 6 7 8 5 6 7 8 C D F A B E www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-P410UB/XS/UC 62 1 2 3 4 1 2 3 4 C D F A B E 11. PCB CONNECTION DIAGRAM 11.1 TUNER AMP ASSY A A TUNER AMP ASSY Capacitor Connector P.C.Board Chip Part SIDE B SIDE A NOTE FOR PCB DIAGRAMS 1.The parts mounted on this PCB include all necessary parts for several destination. For further information for respective destinations, be sure to check with the schematic dia- gram. 2.Viewpoint of PCB diagrams 1 1 10 1 5 1 5 E E 1 1 10 15 IC921 L852 D971 CN803 CN621 CN251 BZ601 L101 Q702 L501 Q911 L901 CN101 R701 L951 CN701 R912 CN901 C501 C502 C313 C703 C708 C911 C913 R955 C922 C923 D502 D701 D901 D90 D903 D904 D911 D912 D931 D932 D551 D552 5 5 10 20 30 40 50 60 70 X 150 140 130 120 110 100 90 80 70 60 50 40 30 20 10 0 Y B CN1801 C CN701 IP-BUS WIRED REM. CORD ASSY 1 2 15 16 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-P410UB/XS/UC 63 5 6 7 8 5 6 7 8 C D F A B E A SIDE A 1 10 1 5 10 15 20 1 1 5 10 1 10 15 20 25 D171 D181 R414 CN401 D971 3 C401 C405 C408 CN622 C605 C607 R454 X601 R843 C451 C842 L101 Y401 D454 D841 D842 L161 R309 L171 L951 C311 CN351 R955 C351C352 C353 C160 C354 C355 C162 C356 C165 C172 C174 C177 C183 L401 L403 IC301 L601 D901 D902 C962 L602 C971 D551 5 70 80 90 100 110 120 130 140 150 160 170 FRONT RCA ANTENNA FM/AM TUNER UNIT SSY 1 2 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-P410UB/XS/UC 64 1 2 3 4 1 2 3 4 C D F A B E A A TUNER AMP ASSY 170 160 150 140 130 120 110 100 90 8 1 5 10 15 20 25 1 5 1 1 1 1 15 25 30 35 40 45 50 55 60 65 70 75 80 85 90 95 100 1 1 1 1 E 1 E E E 1 1 1 E 1 E E 1 E IC151 R401 D172 R402 R403 D173 R404 R405 R406 R407 R408 R409 R601 R602 R603 R410 R604 D951 R411 R605 R412 R606 R413 R607 R608 R415 R609 R803 R610 R804 R611 R805 R612 R613 R614 R808 R421 R809 IC171 R619 R811 R813 R620 R814 R815 R816 R819 R627 R824 R631 C402 R632 C403 C404 IC961 R829 C406 C407 R830 C601 R831 C602 C R833 C410 C604 R834 C411 R835 C412 C606 R837 C608 R451 C609 R452 R453 R841 R842 R844 R845 C623 FU353 C841 ZNR401 IC401 D8 IC601 D621 IC602 D622 D623 Q351 Q352 Q353 R301 R302 R303 R304 Q171 R305 R306 Q172 R113 R307 R308 R507 Q951 Q181 Q182 Q971 C301 C302 C303 C304 C305 C307 C308 R151 C309 R152 R153 C310 R351 C315 R352 C316 R353 C317 R354 C318 R930 R355 R931 R356 R932 R358 C704 R359 C705 R360 R361 R362 R363 R364 R171 R172 R173 R174 R175 R176 R177 R178 R180 R951 R181 R952 R953 R954 R381 C151 R382 C152 C153 R383 R384 C154 R385 C155 R386 R962 C156 C157 C158 C159 R967 R391 R392 R393 C163 C357 R394 C358 C359 C360 C361 C362 C171 Q401 Q402 C173 C175 C176 C178 C179 C181 C182 L402 C961 Q451 Q453 Q841 Q842 Q843 Q844 C306 5 10 20 1 1 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-P410UB/XS/UC 65 5 6 7 8 5 6 7 8 C D F A B E A SIDE B 90 80 70 60 50 40 X 150 140 130 120 110 100 90 80 70 60 50 40 30 20 10 0 Y 30 20 10 E E 1 10 E E 1 1 15 25 30 35 40 45 1 1 1 E 1 5 1 5 1 1 Q851 Q852 R601 R602 IC551 R805 R806 R807 R808 R616 R617 R618 R811 R813 R814 R621 R815 R622 R623 R624 R819 R625 R626 R628 R629 R825 R633 R253 R254 R255 C601 R256 C602 R832 R257 C603 R836 C801 R846 R847 R848 R849 R851 C621 R852 C622 R853 C251 C252 C253 Q101 Q102 C851 Q701 D801 D802 D803 D804 D805 D806 D807 D808 D809 D810 Q912 D251 D252 Q931 R101 R102 R103 R104 R105 R106 R107 R108 R109 R110 R111 R112 R113 R114 R116 R117 R118 IC251 R502 R503 R505 R506 R507 R508 R509 R703 R510 R704 R511 R705 R512 R706 R513 R707 R708 R709 R710 R711 R712 R713 R714 C101 C102 C103 C104 R911 Q971 R922 C503 C504 C505 C506 C507 C508 R931 C701 C702 R933 R934 R935 R936 C706 R937 C707 R938 C709 C901 C710 C711 C715 C716 C912 C720 C721 C921 C924 R967 C931 R971 R972 C551 C552 D501 IC101 IC501 IC702 L251 5 5 10 20 1 1 1 1 1 > FU 353 (B,131,132) Fuse 3 A CEK1286 1 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-P410UB/XS/UC 66 1 2 3 4 1 2 3 4 C D F A B E 11.2 KEYBOARD UNIT B SIDE A B KEYBOARD UNIT OLED AUX EJECT CLOCK RPT SW/BASS RDM S.Rtrv DISP LIST SRC BAND MULTI-CONTROL www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-P410UB/XS/UC 67 5 6 7 8 5 6 7 8 C D F A B E B SIDE B B KEYBOARD UNIT A CN803 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-P410UB/XS/UC 68 1 2 3 4 1 2 3 4 C D F A B E 11.3 CD CORE UNIT(S10.5 iPod-Code2 Class4) C SIDE A C CD CORE UNIT(S10.5 iPod-Code2 Class4) HOME M2 LOADING/CARRIAGE MOTOR M1 SPINDLE MOTOR REFO1 F E A CN701 PICKUP UNIT(P10.5) (SERVICE) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-P410UB/XS/UC 69 5 6 7 8 5 6 7 8 C D F A B E C SIDE B C CD CORE UNIT(S10.5 iPod-Code2 Class4) 8EJ 12EJ DSCSNS www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-P410UB/XS/UC 70 1 2 3 4 1 2 3 4 C D F A B E 12. ELECTRICAL PARTS LIST NOTE: Parts whose parts numbers are omitted are subject to being not supplied. The part numbers shown below indicate chip components. Chip Resistor RS1/_S___J,RS1/__S___J Chip Capacitor (except for CQS.....) CKS....., CCS....., CSZS..... The > mark found on some component parts indicates the importance of the safety factor of the part. Therefore, when replacing, be sure to use parts of identical designation. Meaning of the figures and others in the parentheses in the parts list. Example) IC 301 is on the point (face A, 91 of x-axis, and 111 of y-axis) of the corresponding PC board. IC 301 (A, 91, 111) IC NJM2068V The expression of the unit in this manual is shown by u instead of µ. Please do not make a mistake. Circuit Symbol and No. Part No. Unit Number : YWM5394(P410UB) Unit Number : YWM5392(P4100UB) Unit Number : YWM5396(P4150UB) Unit Name : Tuner Amp Assy Unit Number : (P410UB) Unit Number : (P4100UB) Unit Number : (P4150UB) Unit Name : Keyboard Unit Unit Number : CWX3712 Unit Name : CD Core Unit(S10.5 iPod-Code2 Class4) A Unit Number : YWM5394(P410UB) Unit Number : YWM5392(P4100UB) Unit Number : YWM5396(P4150UB) Unit Name : Tuner Amp Assy MISCELLANEOUS IC 101 (B,77,63) IC HA12241FP IC 151 (B,135,85) IC PML018A IC 171 (B,148,26) IC NJM2360M IC 251 (B,44,69) IC R5523N001B IC 301 (A,105,139) IC PAL007C IC 401 (B,165,29) IC NJM2885DL1-33 IC 501 (B,16,32) Regulator IC BD9781HFP IC 601 (B,96,57) IC PEG407B IC 702 (B,58,29) IC NJM2885DL1-33 IC 921 (A,6,120) IC NJM2388F84 IC 961 (B,98,33) IC S-80835CNMC-B8U Q 101 (B,40,95) Transistor 2SA1576A Q 102 (B,31,115) Transistor RT1N141M-11 Q 171 (B,129,30) Transistor RT3T22M Q 172 (B,126,35) Transistor 2SD1767 Q 181 (B,137,72) Transistor RT3T22M Q 182 (B,130,67) Transistor 2SC4081 Q 351 (B,166,125) Transistor RT3N66M Q 352 (B,140,121) Transistor RT3N66M Q 353 (B,135,125) Transistor RT3N66M Q 451 (B,117,119) Transistor RT1N241M Q 453 (B,116,116) Transistor RT3T22M Q 701 (B,20,60) Transistor RT3T22M Q 702 (A,7,70) Transistor 2SD2396 Q 841 (B,131,23) Transistor 2SA1036K Q 842 (B,139,17) Transistor RT1N141M-11 Q 851 (B,33,15) Transistor 2SA1036K Q 852 (B,24,16) Transistor RT1N141M-11 Q 911 (A,7,104) Transistor 2SD2396 Q 912 (B,16,73) Transistor RT3T22M Q 931 (B,64,94) Transistor RT3CLLM Q 971 (B,87,94) Transistor RT1N141M-11 D 171 (A,131,37) Diode MTZJA10(B) D 172 (B,139,29) Diode RB551V-30 D 173 (B,99,74) Diode MC2848-11 D 181 (A,138,68) Diode HZS12L(B1) D 251 (B,50,60) Varistor EZJZ1V800AM D 252 (B,51,61) Varistor EZJZ1V800AM D 454 (A,94,105) Diode 1SS133 D 501 (B,22,44) Diode RB060L-40 D 502 (A,16,58) Diode S5688G D 701 (A,26,65) Diode HZS7L(C3) D 801 (B,63,6) Varistor EZJZ1V270RM D 802 (B,64,6) Varistor EZJZ1V270RM D 803 (B,68,6) Varistor EZJZ1V270RM D 805 (B,74,6) Varistor EZJZ1V270RM D 806 (B,78,6) Varistor EZJZ1V270RM D 808 (B,72,6) Varistor EZJZ1V270RM D 809 (B,80,14) Varistor EZJZ1V270RM D 901 (A,74,110) Diode S5688G D 902 (A,78,107) Diode S5688G D 903 (A,62,103) Diode S5688G D 904 (A,59,103) Diode S5688G D 911 (A,16,80) Diode S5688G D 912 (A,16,75) Diode HZS6L(B2) Circuit Symbol and No. Part No. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-P410UB/XS/UC 71 5 6 7 8 5 6 7 8 C D F A B E D 931 (A,55,96) Diode HZS7L(C3) D 932 (A,54,93) Diode HZS7L(A1) D 971 (A,68,103) Diode 1SS133 ZNR401 (B,165,113) Surge Protector IMSA-6801-01Y901 L 101 (A,76,68) Inductor LAU2R2K L 161 (A,122,99) Inductor LAU2R2K L 171 (A,146,32) Inductor YTF5001 L 181 (A,138,61) Ferri-Inductor LAU100K L 251 (B,52,55) Inductor DTH1197 L 401 (A,150,90) Inductor LAU1R0K L 402 (B,159,106) Inductor LCTAW220J2520 L 403 (A,156,34) Inductor LAU1R0K L 501 (A,29,40) Inductor YTF5003 L 601 (A,94,41) Ferri-Inductor LAU100K L 602 (A,104,34) Inductor LAU2R2K L 852 (A,37,16) Inductor LAU2R2K L 901 (A,39,102) Choke Coil 600 uH CTH1280 X 601 (A,84,44) Oscillator 15 MHz YSS5002 >FU353 (B,131,132) Fuse 3 A CEK1286 BZ601 (A,29,16) Buzzer CPV1062 Y 401 (A,163,101) FM/AM Tuner Unit CWE2098 RESISTORS R 101 (B,31,122) RS1/16S181J R 102 (B,34,114) RS1/16S222J R 103 (B,25,129) RS1/16S181J R 104 (B,36,134) RS1/16S101J R 105 (B,33,135) RS1/16S101J R 106 (B,30,121) RS1/16S223J R 107 (B,25,125) RS1/16S223J R 108 (B,27,125) RS1/16S102J R 109 (B,28,121) RS1/16S102J R 110 (B,37,96) RS1/16S332J R 111 (B,32,112) RS1/16S562J R 112 (B,74,72) RS1/16S102J R 113 (B,81,66) RS1/16S472J R 114 (B,78,59) RS1/16S472J R 116 (B,31,135) RS1/16S470J R 117 (B,30,135) RS1/16S150J R 118 (B,66,75) RS1/16S0R0J R 151 (B,146,88) RS1/16S102J R 152 (B,147,87) RS1/16S102J R 153 (B,145,86) RS1/16S102J R 171 (B,130,32) RS1/16S122J R 172 (B,123,29) RS1/16S122J R 173 (B,146,31) RS1/16S1R0J R 174 (B,144,30) RS1/16S391J R 175 (B,134,32) RS1/16S821J R 176 (B,134,29) RS1/16S102J R 177 (B,140,34) RS1/10S4701F R 181 (B,133,67) RS1/16S391J R 254 (B,45,72) RS1/16S681J R 257 (B,58,52) RS1/16S103J R 301 (B,124,111) RS1/16S682J R 302 (B,137,109) RS1/16S123J R 303 (B,128,109) RS1/16S682J R 304 (B,140,109) RS1/16S682J R 305 (B,126,109) RS1/16S123J Circuit Symbol and No. Part No. R 306 (B,134,109) RS1/16S682J R 307 (B,123,109) RS1/16S123J R 308 (B,141,109) RS1/16S123J R 309 (A,98,106) RD1/4PU153J R 351 (B,159,114) RS1/16S390J R 352 (B,156,120) RS1/16S0R0J R 353 (B,131,109) RS1/16S390J R 354 (B,132,109) RS1/16S390J R 355 (B,136,121) RS1/16S390J R 356 (B,132,97) RS1/16S390J R 358 (B,131,129) RS1/16S390J R 359 (B,163,133) RS1/16S223J R 360 (B,159,132) RS1/16S223J R 361 (B,158,117) RS1/16S223J R 362 (B,159,136) RS1/16S223J R 363 (B,134,129) RS1/16S223J R 364 (B,137,129) RS1/16S223J R 381 (B,136,129) RS1/16S0R0J R 382 (B,140,125) RS1/16S0R0J R 383 (B,140,123) RS1/16S0R0J R 384 (B,148,117) RS1/16S0R0J R 385 (B,148,116) RS1/16S0R0J R 386 (B,144,123) RS1/16S0R0J R 391 (B,143,126) RS1/16S0R0J R 392 (B,144,129) RS1/16S0R0J R 401 (B,152,54) RS1/16S681J R 403 (B,156,85) RS1/16S681J R 404 (B,157,88) RS1/16S681J R 405 (B,157,90) RS1/16S681J R 406 (B,156,91) RS1/16S681J R 407 (B,156,93) RS1/16S0R0J R 414 (A,157,23) RD1/4PU4R7J R 421 (B,155,86) RS1/16S0R0J R 451 (B,121,117) RS1/16S103J R 452 (B,119,121) RS1/16S221J R 453 (B,121,125) RS1/16S153J R 454 (A,117,111) RD1/4PU102J R 502 (B,26,25) RS1/16S3302F R 503 (B,24,27) RS1/16S333J R 505 (B,28,31) RS1/16S8201F R 506 (B,27,31) RS1/16S683J R 507 (B,82,57) RS1/16S222J R 510 (B,28,45) RS1/16S823J R 511 (B,28,22) RS1/10SR471J R 512 (B,53,21) RS1/16S0R0J R 513 (B,32,22) RS1/16S222J R 602 (B,83,49) RS1/16S103J R 603 (B,98,86) RS1/16S103J R 604 (B,109,62) RS1/16S681J R 605 (B,113,59) RS1/16S681J R 606 (B,103,28) RS1/16S103J R 607 (B,110,60) RS1/16S681J R 608 (B,107,40) (P4100UB,P4150UB) RS1/16S104J R 609 (B,105,43) (P410UB,P4150UB) RS1/16S104J (B,105,43) (P4100UB) RS1/16S473J R 610 (B,106,65) RS1/16S473J R 613 (B,110,83) RS1/16S104J R 616 (B,36,27) RS1/16S473J R 617 (B,42,64) RS1/16S473J R 618 (B,74,59) RS1/16S102J Circuit Symbol and No. Part No. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-P410UB/XS/UC 72 1 2 3 4 1 2 3 4 C D F A B E R 620 (B,109,66) RS1/16S0R0J R 621 (B,14,139) RS1/16S102J R 622 (B,12,139) RS1/16S102J R 627 (B,114,92) RS1/16S102J R 701 (A,16,63) RD1/4PU271J R 703 (B,49,43) RS1/16S472J R 704 (B,32,26) RS1/16S104J R 705 (B,49,46) RS1/16S472J R 706 (B,49,48) RS1/16S104J R 707 (B,36,29) RS1/16S104J R 708 (B,47,50) RS1/16S221J R 709 (B,36,24) RS1/16S102J R 710 (B,49,45) RS1/16S221J R 711 (B,37,40) RS1/16S221J R 712 (B,49,42) RS1/16S221J R 713 (B,35,25) RS1/16S221J R 714 (B,46,53) RS1/16S104J R 806 (B,62,17) RS1/16S222J R 807 (B,62,18) RS1/16S222J R 808 (B,82,39) RS1/16S104J R 816 (B,118,19) RS1/16S1R0J R 825 (B,77,49) RS1/16S102J R 832 (B,49,10) RS1/16S0R0J R 834 (B,128,41) RS1/16S1R0J R 835 (B,101,15) RS1/16S0R0J R 841 (B,134,23) RS1/16S103J R 842 (B,135,23) RS1/16S472J R 851 (B,34,19) RS1/16S153J R 852 (B,24,19) RS1/16S472J R 853 (B,44,8) RS1/16S222J R 911 (B,20,71) RS1/16S223J R 912 (A,16,78) RD1/4PU152J R 922 (B,11,110) RS1/16S473J R 930 (B,107,84) RS1/16S104J R 931 (B,82,50) RS1/16S104J R 932 (B,113,78) RS1/16S104J R 933 (B,64,96) RS1/16S104J R 934 (B,64,98) RS1/16S473J R 935 (B,61,91) RS1/16S473J R 936 (B,60,98) RS1/16S473J R 937 (B,63,117) RS1/16S472J R 938 (B,59,125) RS1/4SA102J R 951 (B,106,106) RS1/16S473J R 962 (B,102,32) RS1/16S822J R 967 (B,90,36) RS1/16S102J R 971 (B,62,125) RS1/4SA102J R 972 (B,75,100) RS1/16S103J CAPACITORS C 101 (B,28,135) CKSRYB104K25 C 104 (B,74,70) CKSRYB103K50 C 151 (B,145,76) CKSRYB105K10 C 152 (B,145,79) CKSRYB105K10 C 153 (B,159,74) CKSRYB224K10 C 154 (B,145,78) CKSRYB105K10 C 155 (B,163,71) CKSRYB224K10 C 156 (B,119,80) CKSRYB105K10 C 157 (B,119,85) CKSRYB105K10 C 158 (B,119,89) CKSRYB105K10 Circuit Symbol and No. Part No. C 159 (B,119,79) CKSRYB105K10 C 160 (A,124,83) CEJQ100M16 C 162 (A,124,89) CEJQ470M10 C 163 (B,124,86) CKSRYB104K25 C 165 (A,135,97) CEJQ100M16 C 171 (B,125,30) CKSRYB104K25 C 172 (A,132,27) CEJQ101M16 C 173 (B,139,22) CKSRYB104K25 C 174 (A,140,24) CEJQ101M16 C 175 (B,140,26) CCSRCH471J50 C 176 (B,138,32) CKSRYB223K50 C 177 (A,135,36) CEJQ470M16 C 181 (B,141,72) CKSRYB473K25 C 182 (B,129,73) CKSRYB104K25 C 183 (A,132,72) CEJQ470M16 C 251 (B,50,68) CKSRYB104K25 C 252 (B,44,63) CKSRYB104K25 C 253 (B,42,65) CKSRYB103K50 C 305 (B,135,113) CKSQYB474K25 C 306 (B,127,113) CKSQYB474K25 C 307 (B,129,113) CKSQYB474K25 C 308 (B,132,113) CKSQYB474K25 C 309 (B,125,134) CKSQYB225K10 C 310 (B,127,132) CKSQYB225K10 C 311 (A,103,127) CEJQ100M16 C 313 (A,51,123) 3 300 uF/16 V CCH1494 C 315 (B,134,117) CKSRYB474K10 C 316 (B,125,114) CKSRYB474K10 C 317 (B,123,114) CKSRYB474K10 C 318 (B,131,117) CKSRYB474K10 C 351 (A,130,97) CEJQ2R2M50 C 352 (A,141,97) CEJQ2R2M50 C 353 (A,135,103) CEJQ2R2M50 C 354 (A,140,103) CEJQ2R2M50 C 355 (A,130,103) CEJQ2R2M50 C 356 (A,147,103) CEJQ2R2M50 C 401 (A,155,55) CEJQ470M6R3 C 402 (B,158,56) CKSRYB103K50 C 403 (B,157,37) CKSRYB103K50 C 405 (A,154,102) CEJQ101M10 C 406 (B,167,94) CKSRYB104K25 C 407 (B,159,68) CKSRYB103K50 C 408 (A,157,29) CEJQ220M10 C 410 (B,157,25) CKSRYB474K10 C 411 (B,167,92) CCSRCH470J50 C 412 (B,128,135) CKSRYB105K10 C 451 (A,119,126) CEJQ330M10 C 501 (A,29,27) 150 uF/6.3 V CCH1781 C 502 (A,17,50) CEJQ221M16 C 503 (B,24,23) CCSRCH221J50 C 504 (B,17,53) CKSRYB105K16 C 505 (B,25,31) CCSRCH101J50 C 506 (B,27,35) CKSRYB332K50 C 507 (B,28,43) CKSRYB104K25 C 508 (B,29,22) CKSRYB105K10 C 601 (B,83,46) CCSRCH180J50 C 602 (B,87,46) CCSRCH180J50 C 603 (B,79,47) CKSRYB105K10 C 604 (B,101,43) CKSRYB105K10 C 605 (A,103,40) CEJQ100M16 Circuit Symbol and No. Part No. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-P410UB/XS/UC 73 5 6 7 8 5 6 7 8 C D F A B E C 606 (B,112,33) CKSRYB104K25 C 607 (A,97,37) CEJQ100M16 C 609 (B,110,64) CCSRCH470J50 C 623 (B,111,93) CKSRYB104K25 C 701 (B,21,57) CKSRYB473K25 C 703 (A,24,53) CEJQ101M10 C 704 (B,145,67) CKSRYB105K10 C 705 (B,127,84) CKSRYB105K10 C 708 (A,39,27) CEJQ220M10 C 709 (B,48,29) CKSRYB105K10 C 710 (B,45,27) CKSRYB474K10 C 720 (B,39,52) CKSRYB105K10 C 851 (B,25,12) CKSRYB104K25 C 901 (B,54,117) CKSRYB104K25 C 911 (A,15,68) CEJQ470M10 C 912 (B,21,73) CKSRYB103K50 C 913 (A,24,74) CEAT102M16 C 921 (B,12,112) CKSRYB103K50 C 922 (A,18,99) CEJQ221M10 C 923 (A,16,117) CEJQ101M16 C 924 (B,15,115) CKSRYB103K50 C 961 (B,101,36) CKSRYB473K25 C 962 (A,93,33) CEJQ100M16 C 971 (A,89,97) CEJQ1R0M50 B Unit Number: (P410UB) Unit Number: (P4100UB) Unit Number: (P4150UB) Unit Name : Keyboard Unit MISCELLANEOUS IC 1801 (A,17,54) Remote IC GP1UXC14RK IC 1802 (B,17,149) IC PEG412A IC 1803 (B,28,106) IC PML019A Q 1802 (B,40,116) Transistor 2SC2412K D 1801 (B,25,133) Diode MC2846-11 D 1802 (B,23,137) Diode MC2848-11 D 1803 (A,6,9) LED CL-197HB1-D(CDE) D 1804 (A,11,6) LED CL-197HB1-D(CDE) D 1805 (A,37,6) LED CL-197HB1-D(CDE) D 1806 (A,37,16) LED CL-197HB1-D(CDE) D 1807 (A,16,16) LED CL-197HB1-D(CDE) D 1808 (A,19,27) LED CL-197HB1-D(CDE) D 1809 (A,38,27) LED CL-197HB1-D(CDE) D 1810 (A,37,41) LED CL-197HB1-D(CDE) D 1811 (A,19,42) LED CL-197HB1-D(CDE) D 1812 (A,39,58) LED CL-197HB1-D(CDE) D 1813 (A,6,147) LED CL-197HB1-D(CDE) D 1817 (B,12,149) Diode 1SS355 D 1833 (B,25,155) Diode MALS068X D 1834 (B,28,160) Diode MALS068X D 1835 (B,28,159) Diode MALS068X X 1801 (B,14,155) Radiator 10.0 MHz CSS1577 S 1801 (A,39,23) Push Switch CSG1155 S 1802 (A,40,7) Push Switch CSG1155 S 1803 (A,9,7) Push Switch CSG1155 S 1804 (A,40,17) Push Switch CSG1155 S 1805 (A,17,23) Push Switch CSG1155 Circuit Symbol and No. Part No. S 1806 (A,9,147) Push Switch CSG1155 S 1807 (A,13,18) Push Switch CSG1155 S 1808 (A,39,54) Push Switch CSG1155 S 1809 (A,17,45) Push Switch CSG1155 S 1810 (A,39,45) Push Switch CSG1155 S 1811 (A,28,34) Rotary Commander(MULTI-CONTROL) CSX1144 RESISTORS R 1801 (B,23,131) RS1/16S222J R 1802 (B,22,133) RS1/16S222J R 1804 (B,22,62) RS1/16S101J R 1805 (B,18,44) RS1/16S103J R 1806 (B,24,62) RS1/16S2R2J R 1807 (B,38,23) RS1/16S102J R 1808 (B,21,22) RS1/16S333J R 1809 (B,31,21) RS1/16S822J R 1810 (B,28,19) RS1/16S332J R 1811 (B,14,43) RS1/16S102J R 1812 (B,25,21) RS1/16S222J R 1813 (B,41,42) RS1/16S103J R 1814 (B,21,135) RS1/16S103J R 1815 (B,17,139) RS1/16S103J R 1816 (B,18,139) RS1/16S103J R 1817 (B,20,137) RS1/16S103J R 1818 (B,41,16) RS1/16S333J R 1819 (B,40,16) RS1/16S822J R 1820 (B,40,19) RS1/16S332J R 1821 (B,38,21) RS1/16S222J R 1822 (B,14,39) RS1/16S333J R 1823 (B,14,18) RS1/16S822J R 1824 (B,15,18) RS1/16S332J R 1825 (B,16,18) RS1/16S222J R 1826 (B,28,14) RS1/4SA562J R 1827 (B,37,17) RS1/4SA562J R 1828 (B,15,26) RS1/4SA562J R 1829 (B,32,16) RS1/4SA562J R 1830 (B,21,16) RS1/4SA562J R 1831 (B,9,152) RS1/4SA822J R 1834 (B,41,129) RS1/16S393J R 1835 (B,38,127) RS1/16S683J R 1836 (B,38,125) RS1/16S682J R 1837 (B,40,119) RS1/16S392J R 1840 (B,41,23) RS1/16S103J R 1841 (B,19,155) RS1/16S473J R 1842 (B,28,142) RS1/16S473J R 1843 (B,12,148) RS1/16S154J R 1844 (B,27,142) RS1/16S473J R 1845 (B,28,136) RS1/16S101J R 1846 (B,29,139) RS1/16S101J R 1847 (B,30,139) RS1/16S101J R 1848 (B,27,139) RS1/16S101J R 1849 (B,26,136) RS1/16S101J R 1850 (B,32,137) RS1/16S1802D R 1852 (B,38,124) RS1/16S0R0J R 1863 (B,32,140) RS1/16S0R0J R 1867 (B,38,111) RS1/16S473J R 1869 (B,21,129) RS1/16S0R0J R 1871 (B,28,151) RS1/16S101J R 1872 (B,30,154) RS1/16S101J Circuit Symbol and No. Part No. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-P410UB/XS/UC 74 1 2 3 4 1 2 3 4 C D F A B E R 1873 (B,27,154) RS1/16S223J R 1874 (B,30,157) RS1/16S223J CAPACITORS C 1804 (B,18,46) CKSYF106Z10 C 1820 (B,41,126) CKSRYB104K50 C 1821 (B,12,151) CKSRYB103K50 C 1824 (B,9,147) CKSRYB104K50 C 1825 (B,38,113) CKSRYB105K10 C 1925 (B,40,42) CKSRYB104K50 C 1931 (B,27,157) CKSRYB472K50 C 1932 (B,31,157) CKSRYB472K50 C Unit Number : CWX3712 Unit Name : CD Core Unit(S10.5 iPod-Code2 Class4) MISCELLANEOUS IC 201 (A,35,46) IC PE5647A IC 205 (B,24,49) IC 341S2159 IC 301 (A,28,15) IC BA5839FP Q 101 (B,58,69) Transistor 2SA1577 Q 102 (B,48,58) Chip Transistor 2SB1689 Q 201 (B,27,54) Transistor 2SA1577 X 201 (A,22,37) Ceramic Resonator 16.934 MHz CSS1603 X 205 (B,33,63) Oscillator 48.000 MHz CSS1753 S 901 (A,55,37) Switch(HOME) CSN1067 S 903 (B,19,58) Switch(DSCSNS) CSN1067 S 904 (B,40,68) Switch(12EJ) CSN1068 S 905 (B,25,69) Switch(8EJ) CSN1068 RESISTORS R 101 (B,61,74) RS1/10SR2R4J R 102 (B,61,72) RS1/10SR2R4J R 103 (B,61,71) RS1/10SR2R7J R 104 (B,53,66) RS1/16SS222J R 105 (B,44,57) RS1/16SS102J R 107 (B,52,60) RS1/16SS105J R 202 (A,27,32) RS1/16SS473J R 203 (A,51,44) RS1/16S473J R 204 (A,23,58) RS1/16SS221J R 206 (B,10,26) RS1/16SS104J R 209 (B,18,52) RS1/16SS103J R 210 (B,10,23) RS1/16SS102J R 214 (B,49,50) RS1/16SS472J R 216 (B,48,49) RS1/16SS472J R 221 (A,51,48) RS1/16SS103J R 222 (A,51,46) RS1/16SS103J R 223 (B,13,43) RS1/16SS473J R 225 (A,50,50) RS1/16SS103J R 226 (A,50,51) RS1/16SS393J R 227 (B,47,51) RS1/16SS562J R 228 (B,44,51) RS1/16SS122J R 229 (B,46,53) RS1/16SS472J R 230 (B,21,25) RS1/16SS0R0J R 232 (B,45,51) RS1/16SS122J R 233 (B,26,59) RS1/16SS103J R 234 (B,22,26) RS1/16SS473J Circuit Symbol and No. Part No. R 235 (A,26,59) RS1/16SS473J R 237 (A,24,35) RS1/16SS151J R 240 (B,14,26) RS1/16S473J R 241 (B,13,25) RS1/16SS103J R 244 (B,22,55) RS1/16SS473J R 249 (B,14,50) RS1/16SS103J R 250 (B,19,50) RS1/16SS101J R 252 (B,18,47) RS1/16SS101J R 254 (A,25,64) RS1/16SS104J R 255 (A,26,63) RS1/16SS104J R 256 (A,25,62) RS1/16SS104J R 259 (A,27,66) RS1/16SS0R0J R 261 (A,26,65) RS1/16SS104J R 262 (A,29,59) RS1/16SS0R0J R 263 (A,27,63) RS1/16SS0R0J R 273 (B,18,48) RS1/16SS103J R 277 (B,18,50) RS1/16SS103J R 282 (A,30,61) RS1/16SS240J R 283 (A,29,61) RS1/16SS240J R 284 (B,29,63) RS1/16SS153J R 285 (B,28,63) RS1/16SS153J R 291 (B,42,62) RS1/16SS272J R 292 (B,24,43) RS1/16SS272J R 293 (B,27,52) RS1/16SS472J R 294 (A,31,62) RS1/16SS471J R 307 (A,35,19) RS1/16SS183J R 308 (A,37,19) RS1/16SS183J R 309 (A,35,21) RS1/16SS183J R 310 (A,37,22) RS1/16SS183J R 601 (B,30,31) RS1/16SS0R0J R 602 (B,27,31) RS1/16SS0R0J R 606 (B,28,23) RS1/16S0R0J R 701 (B,11,37) RS1/16SS221J R 702 (A,23,56) RS1/16SS221J R 708 (B,15,37) RS1/16S0R0J R 712 (B,14,54) RS1/16SS0R0J R 713 (B,14,53) RS1/16SS0R0J CAPACITORS C 106 (B,56,67) CKSQYB475K6R3 C 202 (A,28,57) CKSSYB104K10 C 204 (A,23,59) CKSSYB103K16 C 205 (B,27,41) CKSQYB475K6R3 C 206 (A,23,40) CKSSYB104K10 C 207 (A,24,37) CKSRYB104K16 C 209 (B,35,34) CEVW220M6R3 C 210 (B,29,37) CKSSYB104K10 C 211 (A,28,35) CKSSYB104K10 C 212 (A,28,30) CKSRYB104K16 C 213 (A,46,39) CKSSYB104K10 C 214 (A,29,33) CKSSYB104K10 C 216 (A,51,52) CKSSYB332K50 C 217 (A,48,51) CKSSYB104K10 C 218 (A,50,52) CKSSYB473K10 C 219 (A,47,53) CKSSYB104K10 C 220 (A,48,53) CKSSYB182K50 C 221 (A,46,54) CKSSYB104K10 C 222 (B,45,53) CCSSCH560J50 C 223 (B,47,53) CCSSCH4R0C50 Circuit Symbol and No. Part No. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-P410UB/XS/UC 75 5 6 7 8 5 6 7 8 C D F A B E C 224 (A,44,55) CKSSYB104K10 C 226 (A,42,59) CCSSCH680J50 C 227 (A,42,61) CCSSCH470J50 C 228 (B,41,61) CKSSYB103K16 C 229 (B,48,60) CKSSYB104K10 C 236 (A,49,58) CKSSYB104K10 C 239 (B,46,51) CCSSCH220J50 C 240 (A,38,61) CKSSYB104K10 C 243 (B,22,41) CKSQYB475K6R3 C 250 (A,52,48) CKSSYB102K50 C 251 (A,52,46) CKSSYB102K50 C 260 (A,28,61) CKSSYB104K10 C 261 (B,33,66) CCSSCH8R0D50 C 262 (B,31,66) CCSSCH8R0D50 C 290 (B,26,45) CKSSYB104K10 C 293 (B,43,61) CKSSYB102K50 C 294 (B,24,41) CKSSYB104K10 C 303 (A,36,19) CKSSYB472K25 C 304 (A,36,21) CKSSYB223K16 C 307 (A,22,11) CKSRYB104K16 C 308 (B,11,18) CKSRYB105K10 C 703 (B,14,35) CCSSCH101J50 C 704 (B,11,36) CKSSYB102K50 C 711 (A,31,25) CKSSYB104K10 Miscellaneous Parts List Pickup Unit(P10.5)(Service) CXX1942 M 1 Motor Unit(SPINDLE) CXC7134 M 2 Motor Unit(LOADING/CARRIAGE) CXC4026 Circuit Symbol and No. Part No. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com
