ORDER NO. PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan PIONEER ELECTRONICS SERVICE, INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A. PIONEER ELECTRONIC NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936 � � � � � � � � � �PIONEER CORPORATION 2000 RRV2365 T – ZZR AUG. 2000 Printed in Japan CONTENTS 1. CONTRAST OF MISCELLANEOUS PARTS ........ 2 2. SCHEMATIC DIAGRAM ....................................... 8 AUDIO/VIDEO MULTI-CHANNEL RECEIVER VSX-D709S Model No. Order No. Remarks VSX-35TX/KUXJI/CA RRV2351 ¶ This service manual should be used together with the following manual(s): THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S). Remarks Power Requirement Type Model VSX-D709S KUXJI/CA AC120V www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com VSX-D709S 2 VSX-35TX/KUXJI/CA and VSX-D709S/KUXJI/CA are constructed the same except for the following: PCB ASSEMBLIES NSP MAIN ASSY AWK7591 AWK7615 P5- 5 MAIN CONTROL ASSY AWX7560 AWX7618 P5-17 DSP ASSY AWX7561 AWX7611 NSP COMPLEX ASSY AWK7592 AWK7613 P5- 2 EX I/O(5.1CH I/O) ASSY AWX7568 AWX7613 P5- 6 A-CONNECTION ASSY AWX7566 AWX7619 P5- 9 V-CONNECTION ASSY AWX7567 AWX7717 P5-13 TRANS2- 2 ASSY AWX7565 AWX7720 NSP POWER ASSY AWK7593 AWK7598 P5- 4 INPUT ASSY AWX7573 AWX7585 P5-10 SP/PS ASSY AWX7571 AWX7721 NSP FRONT ASSY AWK7594 AWK7617 P5- 7 COMPOSITE ASSY AWX7581 AWX7617 P5- 8 S VIDEO ASSY AWX7580 AWX7616 P7- 1 DISPLAY ASSY AWX7574 AWX7620 P7- 6 FRONT DIGIN ASSY AWX7648 Not used PACKING SECTION P3- 3 Operating Instructions(English) ARB7222 ARB7224 P3- 4 Remote Control Unit AXD7266 AXD7268 P3- 8 Packing Case AHD7860 AHD7867 P3-11 NSP Warranty Card ARY7007 ARY7045 EXTERIOR SECTION P5-31 Rear Panel ANC7910 ANC7941 P5-41 Teminal Screw AKE-031 Not used FRONT PANEL SECTION P7- 9 4P Flexible Cable/60V ADD7238 Not used P7-12 5P Shield with Housing ADX7344 Not used P7-14 Door AMB7692 AMB7697 P7-19 Digital Cap 35 AAD7576 Not used P7-21 Window AAK7769 AAK7733 P7-22 Door Sheet AAK7783 AAK7780 P7-25 Front Panel AMB7691 AMB7715 1. CONTRAST OF MISCELLANEOUS PARTS Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List. The mark found on some component parts indicates the importance of the safety factor of the part. Therefore, when replacing, be sure to use parts of identical designation. Screws adjacent to mark on product are used for disassembly. Reference Nos. indicate the pages and Nos. in the service manual for the base model. NOTES: When ordering resistors, first convert resistance values into code form as shown in the following examples. Ex.1 When there are 2 effective digits (any digit apart from 0), such as 560 ohm and 47k ohm (tolerance is shown by J=5%, and K=10%). Ex.2 When there are 3 effective digits (such as in high precision metal film resistors). 5 6 1 4 7 3 R 5 0 1 R 0 5 6 2 1 560 47k 0.5 1 RD1/4PU J RD1/4PU J RN2H K RS1P K 56 x 101 47 x 103 R50 1R0 561 473 5.62k RN1/4PC F 562 x 101 5621 CONTRAST TABLE Notes : ÷ For PCB ASSEMBLIES, Refer to “CONTRAST OF PCB ASSEMBLIES”and “2. SCHEMATIC DIAGRAM”. Ref. No. Remarks VSX-35TX VSX-D709S /KUXJI/CA /KUXJI/CA Part No. Mark Symbol and Description www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com VSX-D709S 3 CONTRAST OF PCB ASSEMBLIES AWX7613 and AWX7568 are constructed the same except for the following : EXI I/O (5.1CH I/O) ASSY F B Mark Symbol and Description Part No. Remarks AWX7568 AWX7613 IC1101- IC1103 UPC4570G2 NJM4558MD IC1104 UPC4570G2 Not used Q1157, Q1158 HN1C03F Not used C1115, C1116 CEAT4R7M50 Not used C1131, C1132 CEAT100M50 Not used C1139, C1140 CKSQYB103K50 Not used R1107, R1108 RS1/10S331J Not used R1115, R1116 RS1/10S104J Not used R1125, R1126 RS1/10S474J Not used R1157, R1158 RS1/10S271J Not used R1165, R1166 RS1/10S121J Not used R1173, R1174 RS1/10S101J Not used R1181, R1182, R1189, R1190 RS1/10S103J Not used JA1113, JA1163 AKB7046 Not used AWX7717 and AWX7567 are constructed the same except for the following : V-CONNECTION ASSY F H Mark Symbol and Description Part No. Remarks AWX7567 AWX7717 Q601 KRC103M Not used C601 CKSQYB103K50 Not used CN604 KM200TA10 Not used R601 RS1/10S103J Not used AWX7585 and AWX7573 are constructed the same except for the following : INPUT ASSY F C Mark Symbol and Description Part No. Remarks AWX7573 AWX7585 Q1001, Q1002 2SC7878 Not used D1051 1SS133 Not used C1051 CGCYX103M16 Not used R1013– R1016, R1051 RD1/4PU102J Not used R1017, R1018 RD1/4PU473J Not used CN1002 KP200TA6L Not used JA1004 AKB7046 Not used JA1051 AKN7014 Not used www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com VSX-D709S 4 AWX7720 and AWX7565 are constructed the same except for the following : TRANS 2-2 ASSY F O Mark Symbol and Description Part No. Remarks AWX7565 AWX7720 C5501, C5502 CQMA224J50 Not used R5501 RD1/4MUF100J Not used AWX7619 and AWX7566 are constructed the same except for the following : A-CONNECTION ASSY F E Mark Symbol and Description Part No. Remarks AWX7566 AWX7619 IC1501 TC9215AF Not used IC1502 TC9459F Not used IC1503 NJM4558MD Not used IC1551 M62429FP Not used D1551 UDZS5.1B Not used C1501– C1504, C1517, C1518 CKSQYB103K50 Not used C1507, C1508, C1515, C1516, C1551 CEAT100M50 Not used C1552, C1553 CEAT100M50 Not used C1511, C1512 CCSQCH560J50 Not used C1541– C1543, C1554, C1555 CCSQCH101J50 Not used C1556, C1557 CEAT1R0M50 Not used R1503, R1504, R1511, R1512 RS1/10S104J Not used R1505, R1506, R1554, R1555 RS1/10S103J Not used R1507, R1508 RS1/10S472J Not used R1509, R1510 RS1/10S152J Not used R1541– R1545, R1552, R1553 RS1/10S102J Not used R1551 RS3LMF391J Not used R1569– R1574 RS1/10S0R0J Not used CN1552 AKP7068 Not used CN1554 KM200TA6 Not used AWX7721 and AWX7571 are constructed the same except for the following : SP/PS ASSY F L Mark Symbol and Description Part No. Remarks AWX7571 AWX7721 C3001, C3002 (22000µF/56V) ACH7147 ACH7145 L3111, L3112 ATX1012 Not used www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com VSX-D709S 5 AWX7618 and AWX7560 are constructed the same except for the following : MAIN CONTROL ASSY F D Mark Symbol and Description Part No. Remarks AWX7560 AWX7618 IC101 M5220FP Not used IC103 TC9164AF Not used IC104 NJM4558MD Not used Q905 DTA124EK Not used C113, C114 CEAT100M50 Not used C115, C116 CCSQCH181J50 Not used C117, C118 CEAT470M25 Not used C121, C122 CQMA822J50 Not used C123, C124 CQMA242J50 Not used C125, C126 CEAT2R2M50 Not used C127, C128 CEJQ101M25 Not used C133, C134, C911 CKSRYB103K50 Not used C135, C136 CEAT1R0M50 Not used C191, C192, C153 CCSRCH101J50 Not used R111, R112 RD1/10S0R0J Not used R113, R114, R117, R118, R129, R130 RS1/10S104J Not used R139, R140, R203, R204 RS1/10S104J Not uesd R115, R116 RS1/10S331J Not used R119, R120 RS1/10S511J Not used R121, R122 RS1/10S394J Not used R123, R124 RS1/10S303J Not used R125, R126 RS1/10S471 Not used R131, R132 RS1/16S474J Not used R133, R134 RS1/16S471J Not used R135, R136 RS1/106S102J Not used R921, R923 Not used RS1/16S103J R924 RS1/16S103J Not used R933 RS1/16S473J Not used R934– R946, R990, R991 RS1/16S102J Not used CN103 AKP7057 Not used CN906 52045-0445 Not used JA151 VKB1060 Not used AWX7616 and AWX7580 are constructed the same except for the following : S VIDEO ASSY F G Mark Symbol and Description Part No. Remarks AWX7580 AWX7616 IC852 BU4053BCF Not used C854 CCSQCH151J50 Not used C855, C856 CKSQYB103K50 Not used R855 RS1/10S103J Not used R868– R869 RS1/10S102J Not used R883 Not used RS1/10S0R0J R884 RS1/10S0R0J Not used R885 Not used RS1/10S0R0J www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com VSX-D709S 6 AWX7620 and AWX7574 are constructed the same except for the following : DISPLAY ASSY F S Mark Symbol and Description Part No. Remarks AWX7574 AWX7620 IC7051 TC7W53FU Not used Q7053 FMA1A Not used Q7054 DTC124EK Not used D7054– D7057 1SS355 Not used C7053 CKSQYB153K50 Not used R7056 RS1/10S223J Not used R7057 RS1/10S392J Not used R7058, R7061 RS1/10S103J Not used CN7007 52045-0445 Not used S7003 ASG7013 Not used AWX7617 and AWX7581 are constructed the same except for the following : COMPOSITE ASSY F F Mark Symbol and Description Part No. Remarks AWX7581 AWX7617 IC731 NJM2279M Not used IC751 TC4W53FU Not used Q701 2SA933S Not used D731 DAN202K Not used C707 CCSQCH181J50 Not used C712 CEAT101M10 Not used C713 CEAT101M16 Not used C714, C732, C733, C736, C785, C786 CKSQYB473K50 Not used C715 CCSQCH150J50 Not used C734, C735 CEAT101M10 Not used C737 CCSQCH470J50 Not used R707 RS1/10S750J Not used R712 RS1/10S183J Not used R713 RS1/10S103J Not used R714 RS1/10S101J Not used R715 RD1/2VM201J Not used R733– R735, R766 RS1/10S102J Not used R767 RS1/10S104J Not used 703 AKB7017 Not used JA703 Not used VKB1048 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com VSX-D709S 7 AWX7611 and AWX7561 are constructed the same except for the following : DSP ASSY F Y Mark Symbol and Description Part No. Remarks AWX7561 AWX7611 IC9103 CS4391 Not used IC9602– IC9604 UPC4570G2 NJM4558MD IC9701– IC9705 UPC4570G2 NJM4558MD IC9706, IC9707 UPC4570G2 Not used Q9611, Q9612 2SC3326 Not used L9105, L9106 QTL1013 Not used C9120 CEJA470M16 Not used C9121, C9124, CKSRYB103K50 Not used C9122 CCSRCH471J50 Not used C9123, C9125 CEJA1R0M50 Not used C9126 CKSRYB104K16 Not used C9167 CKSQYF104Z50 Not used C9705, C9706, C9759, C9760 CKSQYF104Z25 Not used C9745, C9746, C9781, C9782 CKSRYB102K50 Not used C9749– C9752 CCSRCH221J50 Not used C9753, C9754 CEJA330M10 Not used C9755, C9756 CKSRYB122K50 Not used C9757, C9758 CCSRCH271J50 Not used C9761, C9762 CEJA4R7M50 Not used C9763, C9764 CKSRYB222K50 Not used R9104 RS1/16S101J RS1/16S331J R9120 RS1/10S681J Not used R9121 RS1/10S562J Not used R9122 RS1/10S681J Not used R9123 RS1/10S182J Not used R9154 RS1/10S104J RS1/10S0R0J R9173 RS1/10S0R0J Not used R9577 RS1/16S331J Not used R9737– R9742, R9753, R9754, R9763, R9764 RS1/16S153J Not used R9743– R9746, R9755, R9756 RS1/16S332J Not used R9747, R9748 RS1/16S122J Not used R9749, R9750 RS1/16S562J Not used R9751, R9752 RS1/16S822J Not used R9757, R9758 RS1/16S474J Not used R9759, R9760 RS1/16S101J Not used CN9804 S5B-PH-K-S Not used JA9156 GP1FA551TZ Not used www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com VSX-D709S 8 A B C D 1 2 3 4 1 2 3 4 2. SCHEMATIC DIAGRAM 2.1 EXTRA I/O(5.1 CH I/O) and MAIN CONTROL ASSYS F B : AUDIO SIGNAL ROUTE JA1111 : AKB7048 JA1113 : AKB7046 5.1CH I/O ASSY (VSX-D709 : AWX7613) CN1503 E CN1501 E CN1505 E PREOUT MUTE B F www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com VSX-D709S 9 A B C D 1 2 3 4 1 2 3 4 R921 : 10 kΩ R923 : 10 kΩ ∗1 ∗1 ∗1 TU TU 3/3F MAIN CONTROL ASSY (VSX-D709S : AWX7618) D 3/3F D www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com VSX-D709S 10 A B C D 1 2 3 4 1 2 3 4 F G 2.2 S VIDEO and TRANS 2-2 ASSY VSX-D709S Not used Y C C Y Y Y Y Y Y C C OSD SELECTOR F S VIDEO ASSY (VSX-D709S : AWX7616) G TRANS 2-2 ASSY (VSX-D709S:AWX7720) POWER TRANSFORMER (ATS7284) N 5010 F TRANS 2-2 ASSY (VSX-D709S : AWX7720) O F O www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com VSX-D709S 11 A B C D 1 2 3 4 1 2 3 4F F 2.3 COMPOSITE ASSY JA704 : AKB7056 Not used Not used Not used JA702 : AKB7056 JA703 VSX-D709S: VKB1048 VSX-35TX : AUDIO SIGNAL ROUTE COMPOSITE ASSY (VSX-D709S : AWX7617) CN602 OSD SELECTOR H F F www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com VSX-D709S 12 A B C D 1 2 3 4 1 2 3 4 2/5F Y 2.4 DSP ASSY (2/5) R9154 VSX-D709S: 0 Y 4/5MF 2/5F DSP ASSY (VSX-D709S : AWX7611) Y www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com VSX-D709S 13 A B C D 1 2 3 4 1 2 3 4 2/5F Y D/A CONVERTER for SB ch * * 2/5F DSP ASSY (VSX-D709S : AWX7611) Y R9104 330Ω www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com
