PIONEER CORPORATION 4-1, Meguro 1-Chome, Meguro-ku, Tokyo 153-8654, Japan PIONEER ELECTRONICS (USA) INC. P.O.Box 1760, Long Beach, CA 90801-1760 U.S.A. PIONEER EUROPE NV Haven 1087 Keetberglaan 1, 9120 Melsele, Belgium PIONEER ELECTRONICS ASIACENTRE PTE.LTD. 253 Alexandra Road, #04-01, Singapore 159936 C PIONEER CORPORATION 2004 K-ZZB. APR. 2004 Printed in Japan ORDER NO. CRT3180 POWER AMPLIFIER GM-8437ZT WL Service Manual TOYOTA VEHICLE DESTINATION PRODUCED AFTER TOYOTA PART No. ID No. PIONEER MODEL No. CROWN Singapore, Hong Kong, December 2004 86280-30470 GM-8473ZT/WL Thailand, Indonesia GM-8437ZT/WL For details, refer to "Important symbols for good services". www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 2 1 2 3 4 1 2 3 4 F E D C B A GM-8437ZT/WL [ Important symbols for good services ] In this manual, the symbols shown-below indicate that adjustments, settings or cleaning should be made securely. When you find the procedures bearing any of the symbols, be sure to fulfill them: 2. Adjustments To keep the original performances of the product, optimum adjustments or specification confirmation is indispensable. In accordance with the procedures or instructions described in this manual, adjustments should be performed. 3. Cleaning For optical pickups, tape-deck heads, lenses and mirrors used in projection monitors, and other parts requiring cleaning, proper cleaning should be performed to restore their performances. 5. Lubricants, glues, and replacement parts Appropriately applying grease or glue can maintain the product performances. But improper lubrication or applying glue may lead to failures or troubles in the product. By following the instructions in this manual, be sure to apply the prescribed grease or glue to proper portions by the appropriate amount.For replacement parts or tools, the prescribed ones should be used. 4. Shipping mode and shipping screws To protect the product from damages or failures that may be caused during transit, the shipping mode should be set or the shipping screws should be installed before shipping out in accordance with this manual, if necessary. 1. Product safety You should conform to the regulations governing the product (safety, radio and noise, and other regulations), and should keep the safety during servicing by following the safety instructions described in this manual. SAFETY INFORMATION This service manual is intended for qualified service technicians; it is not meant for the casual do-it-yourselfer. Qualified technicians have the necessary test equipment and tools, and have been trained to properly and safely repair complex products such as those covered by this manual. Improperly performed repairs can adversely affect the safety and reliability of the product and may void the warranty. If you are not qualified to perform the repair of this product properly and safely, you should not risk trying to do so and refer the repair to a qualified service technician. NOTE: - When diagnosing a product, take care of its heated portion. Power IC (IC802,803) Power Supply IC (IC901,902) DSP IC (IC301,311) Heat Sink IC Holder - Service Precaution You should conform to the regulations governing the product (safety, radio and noise, and other regulations), and should keep the safety during servicing by following the safety instructions described in this manual. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 3 5 6 7 8 F E D C B A 5 6 7 8 GM-8437ZT/WL CONTENTS SAFETY INFORMATION............................................2 1. SPECIFICATIONS.......................................................3 2. EXPLODED VIEWS AND PARTS LIST ......................4 2.1 EXTERIOR............................................................4 3. BLOCK DIAGRAM AND SCHEMATIC DIAGRAM ....6 3.1 BLOCK DIAGRAM ...............................................6 3.2 SCHEMATIC DIAGRAM(GUIDE PAGE) ..............8 4. PCB CONNECTION DIAGRAM................................14 4.1 DSP UNIT...........................................................14 4.2 AMP ASSY.........................................................18 4.3 ASL UNIT...........................................................22 5. ELECTRICAL PARTS LIST........................................23 6. ADJUSTMENT.........................................................28 7. GENERAL INFORMATION.......................................30 7.1 DIAGNOSIS .......................................................30 7.1.1 DISASSEMBLY.........................................30 7.1.2 CONNECTOR FUNCTION DESCRIPTION ......32 7.1.3 THE METHOD OF DISTINGUISHING DEFECTIVE DSP IC(IC301 OR IC311) DURING DSP ERROR.....33 7.2 IC ........................................................................35 7.3 EXPLANATION...................................................40 7.3.1 SYSTEM BLOCK DIAGRAM.....................40 7.3.2 OPERATIONAL FLOW CHART .................41 8. OPERATIONS...........................................................41 1. SPECIFICATIONS Power source . . . . . . . . . . . . .13.2±0.1V(10.5-16.0V) Grounding . . . . . . . . . . . . . . . .Negative type Backup current . . . . . . . . . . . .0.3mA or less Dimensions . . . . . . . . . . . . . . .235mm(W)x51mm(H)x128mm(D) Weight . . . . . . . . . . . . . . . . . . .1348g Maximum output power . . . .22W or more(Front) 11W or more(Center) 22W or more(Rear) 35W or more(Woofer) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 4 1 2 3 4 1 2 3 4 F E D C B A GM-8437ZT/WL 2. EXPLODED VIEWS AND PARTS LIST 2.1 EXTERIOR www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 5 5 6 7 8 F E D C B A 5 6 7 8 GM-8437ZT/WL 1 Screw AMZ30P220FTC 2 Screw BSZ26P060FTC 3 Chassis CNA2493 4 Case CNB2743 5 Shield Case CND1276 6 Seal CNM6686 7 Insulator CNM7999 8 Heat Sink CNR1641 9 Amp Assy CWM8256 10 Screw BSZ26P080FTC 11 Screw(M3x6) CBA1393 12 Connector(CN901) CKM1363 13 Connector(CN902) CKM1364 14 Plug(CN905) CKS4569 15 Plug(CN906) CKS4569 16 Connector(CN404) CKS4639 17 Bracket CNC9890 18 Holder CNC9893 19 Holder CND1275 20 Sheet CNM7015 21 DSP Unit CWM8259 22 Socket(CN101) CKS4616 23 Socket(CN102) CKS4616 24 ASL Unit CWM8925 25 Connector(CN403) CKS4605 26 Screw IMS26P060FTC 27 IC(IC802,803) PAL006A 28 IC(IC902) BA178M05T NOTE: - Parts marked by “*” are generally unavailable because they are not in our Master Spare Parts List. - Screws adjacent to ∇ mark on the product are used for disassembly. - For the applying amount of lubricants or glue, follow the instructions in this manual. ( In the case of no amount instructions, apply as you think it appropriate.) - EXTERIOR SECTION PARTS LIST Mark No. Description Part No. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 13 11 10 4 13 11 10 4 1 14 7 10 12 3 18 5 12 9 16 7 IC251 AK4529XQ IC551 PM0017AM IC101 IC186 S-80835CNUA-B8U IC902 BA178M05T IC901 NJM2930F08K Q904 Q906 5V REGULATOR 8V REGULATOR µCOM VDD BALANCE→UNBALANCE INPUT CONNECTOR OUTPUT CONNECTOR IC501 NJM4580MD IC802 PAL006A POWER AMP POWER AMP GAIN ADJ IC751 NJM4580MD 17 19 7 5 12 23 21 1 7 2 6 1 3 1 3 SYS4 BU1 STBY1 BU1 BU1 BU1 FL- FL+ IC803 PAL006A RL- RL+ CN901 R+ L+ MUTE ACC 31 32 ASEN ASEN BSEN asens bsens Q922 Q921 17 16 RESET 1 reset 9 2 SYSTEM CONTROLLER SYSPW1 SYS1 SYS5 SYSD5 1 18 17 2 SYSA5 VA5 VD5 3 3 Q908 SYSPW 66 4 STBY1 4 MUTEO MUTO 40 MUTE MUTIN MUTI 31 SMUTEIN BSENSE MUTE VDD5 VDD5 VDD 1 1 BEEP 21 ACC SENSE BACK UP SENSE SYSTEM MUTE BEEP SYS1 CN906 CN101 CN905 CN102 CN902 ELECTRONIC VOLUME ASLIN 74 IC191 HA12187FP BUS DRIVER AVCIN AVCOUT AVCPW 22 23 2 1 5 8 11 10 12 XOUT XIN IC321 7 20 RLO RLIN 18 FLO FLIN 22 WFO WFIN (FLM) (FLP) LIN RIN IN5 IN1 OUT5 OUT1 15 B A DSP UNIT AMP ASSY 5 5 22 PMUT STBY1 22 PMUT (ASL1) SPD (SPD) Q907 11 8 SPD1 SPD1 SPEED PULSE SENSE 15 SPEED 6 TXH TXP TX+ A/D & D/A IC351 NJM4580MD FRONT LPF 2 1 OUT3 (CTR-) (CTR+) IC62C1024AL-70TI DACCSN,DACCLK,DACDTI,SMUT,PDN 1 IC271 TC7WU04F 7 X271 IC402 NJM4580MD Q401 MIC MIC401 VR401 3 8 IC401 NJM4580MD 5 8 ASL 7 7 3 4 2 1 C ASL UNIT CN404 CN403 SYS8 1 5 ASL1 ASL1 S-812C56AUA-C3K 2 3 Q901 SYS8 Q833 10 Q832 10 Q831 PMUT Q633 VDD5 SYS8 VDD5 9 10 TXL TXM TX- (BEEP) BSEN (ACC) Q601 SWDVDD 20 8 SWDVDD (TX+) (TX-) Q905 VDD5 SWDVDD Q909 PD5769B Q101 VDD5 Q102 X101 LINP RINP LIN RIN Q631 SWITCHED 5V SYS801 SYS8 6 6 GAIN ADJ IC701 NJM4580MD 1 3 2 BEEP BEEP 6 SYS4 LOUT ROUT 5 IC361 NJM4580MD REAR LPF 2 1 3 IC371 NJM4580MD WOOFER LPF 2 1 IN3 27 25 23 (FL) (RL) (CTR) IC301 AK7706VTA IC311 AK7706VTA A0-16 IO0-7 we,oe VDD5 DSP LOUT1 LOUT2 LOUT3 MCLK1 MCLK3 MCLK2 39 16 16 2 VDD5 8 DATA,BCK,LRCK Q632 IC903 Q902 Q903 ACC 8 SWITCHED 5V SYSTEM POWER 6 13 HSW HSW 64 calib Q634 SYSTEM MUTE MUTE IC640 NJM4580MD VOICE INTERRUPTION INPUT DIFFERENTIAL OPERATIONAL AMPLIFIER INT1+ 3 SYS8 8 5 IC451 TC74HC4066AFT 1 2 IC461 TC74HC4066AFT 1 2 IC471 TC7W66FU 1 2 6 ROUT3 24 (WF) EXTERNAL INPUT CHANGE (FL) (RL) (CTR) IN2 4 (WF) 7 MUTE FOR EXTERNAL INPUT CHANGE 21 OUT2 CTRO 9 9 12 14 CTRIN 3 5 (RL+) (RL-) CTR- CTR+ 3 5 (WF-) (WF+) WF- WF+ A A Q803 Q802 FSW FSW Q913 PWSENS 65 5 14 FS FS FSW OUTPUT OFFSET INDICATION XTI 44 46 FLMUTE RLMUTE 48 WFMUTE 47 CTRMUTE (FL) (RL) (CTR) (WF) Q851 6V REG. VCC 1 2 2 ASL1 INT1O INT1IN 4 4 5 TELMUTE 36 TMUT TMUTEIN 2 17 B Q621 TEL MUTE TMUT B 6 1 2 3 4 1 2 3 4 F E D C B A GM-8437ZT/WL 3. BLOCK DIAGRAM AND SCHEMATIC DIAGRAM 3.1 BLOCK DIAGRAM www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 7 5 6 7 8 F E D C B A 5 6 7 8 GM-8437ZT/WL www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 8 1 2 3 4 1 2 3 4 F E D C B A GM-8437ZT/WL A-a A-a A-b A-b A-a A-a A-b A-b A-b A-b A-a A-a Large size SCH diagram Guide page Detailed page Note: When ordering service parts, be sure to refer to " EXPLODED VIEWS AND PARTS LIST" or "ELECTRICAL PARTS LIST". A-a A B C SIGNAL INPUT OFF CIRCUIT TO SUDDEN DECREASE VOLTAGE GAIN ADJUSTMENT BALANCE UNBALANCE AUDIO INPUT DIFFERENTIAL OPERATIONAL AMPLIFIER VOICE INTERRUPTION INPUT DIFFERENTIAL OPERATIONAL AMPLIFIER (BALANCE) C ASL UNIT B AMP ASSY CD:-3.5dBs CD:+8.2dBs (1kHz, 0dB) CD:+1.7dBs 3.2 SCHEMATIC DIAGRAM (GUIDE PAGE) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 9 5 6 7 8 F E D C B A 5 6 7 8 GM-8437ZT/WL A-b A B EXTERNAL INPUT CHANGE MUTE FOR EXTERNAL INPUT CHANGE SPEED PULSE SENSE OUTPUT OFFSET INDICATION OUTPUT OFFSET INDICATION MUTE OUTPUT OFFSET INDICATION OUTPUT OFFSET INDICATION A DSP UNIT Decimal points for resistor and capacitor fixed values are expressed as : 2.2 2R2 0.022 R022 ← ← Symbol indicates a resistor. No differentiation is made between chip resistors and discrete resistors. NOTE : Symbol indicates a capacitor. No differentiation is made between chip capacitors and discrete capacitors. MAY DAY MUTE (HELP NET MUTE) CD:+27.7dBs CD:-5.87dBs CD:+2.0dBs www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 10 1 2 3 4 1 2 3 4 F E D C B A GM-8437ZT/WL A-a A-b A-a A-a A-b C 1 2 C CD:-3.5dBs www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 11 5 6 7 8 F E D C B A 5 6 7 8 GM-8437ZT/WL A-a A-b A-a A-a B A-a B 3 4 SIGNAL INPUT OFF CIRCUIT TO SUDDEN DECREASE VOLTAGE GAIN ADJUSTMENT BALANCE UNBALANCE AUDIO INPUT DIFFERENTIAL OPERATIONAL AMPLIFIER VOICE INTERRUPTION INPUT DIFFERENTIAL OPERATIONAL AMPLIFIER (BALANCE) C ASL UNIT B AMP ASSY CD:+8.2dBs (1kHz, 0dB) CD:+1.7dBs www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 12 1 2 3 4 1 2 3 4 F E D C B A GM-8437ZT/WL A-a A-b A-b 1 2 EXTERNAL INPUT CHANGE MUTE FOR EXTERNAL INPUT CHANGE A DSP UNIT CD:-5.87dBs CD:+2.0dBs www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 13 5 6 7 8 F E D C B A 5 6 7 8 GM-8437ZT/WL A-a A-b A-a B 3 4 SPEED PULSE SENSE OUTPUT OFFSET INDICATION OUTPUT OFFSET INDICATION MUTE OUTPUT OFFSET INDICATION OUTPUT OFFSET INDICATION MAY DAY MUTE (HELP NET MUTE) Decimal points for resistor and capacitor fixed values are expressed as : 2.2 2R2 0.022 R022 ← ← Symbol indicates a resistor. No differentiation is made between chip resistors and discrete resistors. NOTE : Symbol indicates a capacitor. No differentiation is made between chip capacitors and discrete capacitors. CD:+27.7dBs www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 14 1 2 3 4 1 2 3 4 F E D C B A GM-8437ZT/WL 4. PCB CONNECTION DIAGRAM 4.1 DSP UNIT Capacitor Connector P.C.Board Chip Part A A DSP UNIT SIDE B SIDE A NOTE FOR PCB DIAGRAMS 1.The parts mounted on this PCB include all necessary parts for several destination. For further information for respective destinations, be sure to check with the schematic dia- gram. 2.Viewpoint of PCB diagrams B CN906 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 15 5 6 7 8 F E D C B A 5 6 7 8 GM-8437ZT/WL A SIDE A B CN905 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 16 1 2 3 4 1 2 3 4 F E D C B A GM-8437ZT/WL A A DSP UNIT www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 17 5 6 7 8 F E D C B A 5 6 7 8 GM-8437ZT/WL A SIDE B www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 18 1 2 3 4 1 2 3 4 F E D C B A GM-8437ZT/WL 4.2 AMP ASSY B B AMP ASSY A CN101 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 19 5 6 7 8 F E D C B A 5 6 7 8 GM-8437ZT/WL B SIDE A A CN102 C CN403 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 20 1 2 3 4 1 2 3 4 F E D C B A GM-8437ZT/WL B B AMP ASSY www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 21 5 6 7 8 F E D C B A 5 6 7 8 GM-8437ZT/WL B SIDE B www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 22 1 2 3 4 1 2 3 4 F E D C B A GM-8437ZT/WL 4.3 ASL UNIT C C ASL UNIT C ASL UNIT SIDE A SIDE B B CN404 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 23 5 6 7 8 F E D C B A 5 6 7 8 GM-8437ZT/WL Unit Number : CWM8259 Unit Name : DSP Unit MISCELLANEOUS IC 101 IC PD5769B IC 186 IC S-80835CNUA-B8U IC 191 IC HA12187FP IC 251 IC AK4529XQ IC 271 IC TC7WU04F IC 301 IC AK7706VTA IC 311 IC AK7706VTA IC 321 IC IC62C1024AL-70TI IC 351 IC NJM4580MD IC 361 IC NJM4580MD IC 371 IC NJM4580MD IC 451 IC TC74HC4066AFT IC 461 IC TC74HC4066AFT IC 471 IC TC7W66FU IC 551 IC PM0017AM Q 101 Transistor DTA144EU Q 102 Transistor DTC144TU Q 451 Transistor FMG12 Q 453 Transistor DTA114EU Q 454 Transistor DTA114EU Q 461 Transistor FMG12 Q 463 Transistor DTA114EU Q 464 Transistor DTA114EU Q 471 Transistor FMG12 Q 473 Transistor DTA114EU Q 474 Transistor DTA114EU Q 851 Transistor 2SC4081 D 181 Diode 1SS355 D 182 Diode 1SS355 D 801 Diode HZU3R3(B1) D 851 Diode HZU6R8(B2) L 101 Inductor LCTC1R0K2125 L 191 Inductor CTF1305 L 192 Inductor CTF1305 L 251 Inductor LCTC1R0K2125 L 252 Inductor LCTC1R0K2125 L 271 Inductor LCTC1R0K2125 L 301 Inductor LCTCR82K2125 L 311 Inductor LCTCR82K2125 L 321 Inductor LCTCR82K2125 L 811 Inductor LCTC1R0K3216 L 812 Inductor LCTC1R0K3216 L 821 Inductor LCTA2R2J2520 L 822 Inductor LCTA2R2J2520 X 101 Radiator 10.0MHz CSS1607 X 271 Radiator 22.5792MHz CSS1597 RESISTORS R 101 RS1/16S102J R 102 RS1/16S473J R 103 RS1/16S103J R 104 RS1/16S102J R 105 RS1/16S473J R 107 RS1/16S102J R 108 RS1/16S102J R 109 RS1/16S681J R 110 RS1/16S102J R 111 RS1/16S473J R 112 RS1/16S104J R 113 RS1/16S104J R 116 RS1/16S472J R 117 RS1/16S102J R 118 RS1/16S103J R 119 RS1/16S102J R 120 RS1/16S103J R 121 RS1/16S102J R 122 RS1/16S472J R 123 RS1/16S473J R 124 RS1/16S473J R 125 RS1/16S473J R 126 RS1/16S473J R 127 RS1/16S102J R 128 RS1/16S473J R 130 RS1/16S473J R 133 RS1/16S0R0J R 137 RS1/16S102J R 138 RS1/16S102J R 139 RS1/16S102J R 140 RS1/16S102J R 141 RS1/16S102J R 142 RS1/16S102J R 147 RS1/16S102J R 148 RS1/16S102J R 149 RS1/16S102J R 150 RS1/16S102J R 151 RS1/16S102J R 152 RS1/16S102J R 153 RS1/16S102J R 154 RS1/16S102J R 155 RS1/16S102J R 156 RS1/16S102J R 157 RS1/16S102J R 158 RS1/16S473J R 159 RS1/16S102J R 160 RS1/16S102J R 161 RS1/16S102J R 162 RS1/16S102J R 163 RS1/16S102J 5. ELECTRICAL PARTS LIST NOTE: - Parts whose parts numbers are omitted are subject to being not supplied. - The part numbers shown below indicate chip components. Chip Resistor RS1/_S___J,RS1/__S___J Chip Capacitor (except for CQS.....) CKS....., CCS....., CSZS..... =====Circuit Symbol and No.===Part Name Part No. --- ------ ------------------------------------------ ------------------------- =====Circuit Symbol and No.===Part Name Part No. --- ------ ------------------------------------------ ------------------------- A www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 24 1 2 3 4 1 2 3 4 F E D C B A GM-8437ZT/WL R 164 RS1/16S102J R 165 RS1/16S102J R 166 RS1/16S102J R 167 RS1/16S103J R 168 RS1/16S102J R 169 RS1/16S103J R 170 RS1/16S473J R 171 RS1/16S473J R 172 RS1/16S473J R 173 RS1/16S473J R 182 RS1/16S473J R 184 RS1/16S1003D R 185 RS1/16S1003D R 186 RS1/16S104J R 191 RS1/16S102J R 192 RS1/16S102J R 193 RS1/16S473J R 201 RS1/16S102J R 203 RS1/16S102J R 204 RS1/16S102J R 205 RS1/16S102J R 206 RS1/16S102J R 207 RS1/16S102J R 208 RS1/16S102J R 209 RS1/16S102J R 210 RS1/16S272J R 251 RS1/16S102J R 252 RS1/16S102J R 253 RS1/16S102J R 261 RS1/16S101J R 262 RS1/16S101J R 271 RS1/16S105J R 272 RS1/16S680J R 273 RS1/16S471J R 301 RS1/16S221J R 302 RS1/16S221J R 303 RS1/16S221J R 321 RS1/16S102J R 322 RS1/16S102J R 323 RS1/16S102J R 324 RS1/16S102J R 325 RS1/16S102J R 326 RS1/16S473J R 327 RS1/16S102J R 328 RS1/16S102J R 329 RS1/16S102J R 330 RS1/16S102J R 331 RS1/16S102J R 332 RS1/16S102J R 333 RS1/16S102J R 334 RS1/16S102J R 335 RS1/16S102J R 336 RS1/16S102J R 337 RS1/16S102J R 338 RS1/16S102J R 339 RS1/16S102J R 340 RS1/16S102J R 341 RS1/16S102J R 342 RS1/16S102J R 343 RS1/16S102J R 344 RS1/16S102J R 345 RS1/16S102J R 346 RS1/16S102J R 347 RS1/16S102J R 348 RS1/16S102J R 351 RS1/16S332J R 352 RS1/16S332J R 353 RS1/16S183J R 354 RS1/16S183J R 355 RS1/16S822J R 356 RS1/16S822J R 357 RS1/16S273J R 358 RS1/16S273J R 359 RS1/16S103J R 360 RS1/16S103J R 361 RS1/16S332J R 362 RS1/16S332J R 363 RS1/16S183J R 364 RS1/16S183J R 365 RS1/16S822J R 366 RS1/16S822J R 367 RS1/16S273J R 368 RS1/16S273J R 369 RS1/16S103J R 370 RS1/16S103J R 371 RS1/16S332J R 372 RS1/16S332J R 373 RS1/16S183J R 374 RS1/16S183J R 375 RS1/16S822J R 376 RS1/16S822J R 377 RS1/16S273J R 378 RS1/16S273J R 379 RS1/16S103J R 380 RS1/16S103J R 391 RS1/16S101J R 392 RS1/16S101J R 393 RS1/16S101J R 394 RS1/16S101J R 395 RS1/16S101J R 396 RS1/16S101J R 451 RS1/16S472J R 452 RS1/16S472J R 453 RS1/16S104J R 454 RS1/16S104J R 455 RS1/16S102J R 456 RS1/16S102J R 457 RS1/16S472J R 458 RS1/16S472J R 461 RS1/16S472J R 462 RS1/16S472J R 463 RS1/16S104J R 464 RS1/16S104J R 465 RS1/16S102J R 466 RS1/16S102J R 467 RS1/16S472J R 468 RS1/16S472J R 471 RS1/16S472J R 472 RS1/16S472J R 473 RS1/16S104J R 474 RS1/16S104J R 475 RS1/16S102J R 476 RS1/16S102J R 477 RS1/16S472J R 478 RS1/16S472J R 801 RS1/16S271J R 802 RS1/16S121J R 851 RS1/16S271J =====Circuit Symbol and No.===Part Name Part No. --- ------ ------------------------------------------ ------------------------- =====Circuit Symbol and No.===Part Name Part No. --- ------ ------------------------------------------ ------------------------- www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 25 5 6 7 8 F E D C B A 5 6 7 8 GM-8437ZT/WL CAPACITORS C 101 CEVW100M16 C 102 CEVW100M16 C 103 CKSRYB105K10 C 104 CKSRYB103K50 C 105 CKSRYB103K50 C 106 CKSRYB102K50 C 107 CKSRYB102K50 C 186 CKSRYB102K50 C 187 CKSRYB103K50 C 191 CKSRYB103K50 C 251 CEVW100M16 C 252 CKSRYB104K16 C 253 CEVW100M16 C 254 CKSRYB104K16 C 255 CEVW2R2M50 C 256 CKSRYB104K16 C 261 CCSRCH101J50 C 262 CCSRCH101J50 C 263 CEVWNP2R2M35 C 264 CEVWNP2R2M35 C 271 CEVW100M16 C 272 CEVW100M16 C 273 CKSRYB103K50 C 275 CKSRYB102K50 C 276 CKSRYB102K50 C 301 CEVW100M16 C 302 CEVW100M16 C 303 CKSRYB103K50 C 304 CKSRYB104K16 C 305 CKSRYB104K16 C 306 CKSRYB104K16 C 307 CKSRYB104K16 C 308 CKSRYB104K16 C 311 CEVW100M16 C 312 CEVW100M16 C 313 CKSRYB103K50 C 314 CKSRYB104K16 C 315 CKSRYB104K16 C 316 CKSRYB104K16 C 317 CKSRYB104K16 C 318 CKSRYB104K16 C 321 CEVW100M16 C 322 CEVW100M16 C 323 CKSRYB103K50 C 351 CKSRYB182K50 C 352 CKSRYB182K50 C 353 CEVWNP100M16 C 354 CEVWNP100M16 C 355 CKSRYB102K50 C 356 CKSRYB102K50 C 357 CCSRCH101J50 C 358 CCSRCH101J50 C 359 CKSRYB103K50 C 361 CKSRYB182K50 C 362 CKSRYB182K50 C 363 CEVWNP100M16 C 364 CEVWNP100M16 C 365 CKSRYB102K50 C 366 CKSRYB102K50 C 367 CCSRCH101J50 C 368 CCSRCH101J50 C 369 CKSRYB103K50 C 371 CKSRYB182K50 C 372 CKSRYB182K50 C 373 CEVWNP100M16 C 374 CEVWNP100M16 C 375 CKSRYB102K50 C 376 CKSRYB102K50 C 377 CCSRCH101J50 C 378 CKSRYB472K50 C 379 CKSRYB103K50 C 451 4.7µF/25V CCH1451 C 452 4.7µF/25V CCH1451 C 453 CEVW220M10 C 454 CEVW220M10 C 461 4.7µF/25V CCH1451 C 462 4.7µF/25V CCH1451 C 463 CEVW220M10 C 464 CEVW220M10 C 471 4.7µF/25V CCH1451 C 472 4.7µF/25V CCH1451 C 473 CEVW220M10 C 474 CEVW220M10 C 551 CKSYB105K16 C 552 CKSYB105K16 C 553 CKSYB105K16 C 554 CKSYB105K16 C 555 CKSYB105K16 C 556 CKSYB105K16 C 561 CEVWNP2R2M35 C 562 CEVWNP2R2M35 C 563 CEVWNP2R2M35 C 564 CEVWNP2R2M35 C 565 CEVWNP2R2M35 C 566 CEVWNP2R2M35 C 572 CKSRYB104K16 C 573 CEVW100M16 C 574 CKSRYB473K50 C 591 CEVW100M50 C 801 CEVW101M16 C 802 CKSRYB102K50 C 811 CKSRYB103K50 C 812 CKSRYB103K50 C 821 CKSRYB103K50 C 822 CKSRYB103K50 C 831 CKSRYB103K50 C 851 CEVW100M16 C 852 CKSRYB103K50 C 853 CKSRYB103K50 C 854 CKSRYB103K50 C 901 CKSRYB102K50 C 902 CKSRYB102K50 C 903 CKSRYB102K50 C 904 CKSRYB102K50 C 905 CKSRYB102K50 C 907 CKSRYB102K50 Unit Number : CWM8925 Unit Name : ASL Unit MISCELLANEOUS IC 401 IC NJM4580MD IC 402 IC NJM4580MD Q 401 Transistor 2SC4081 D 401 Diode HZU4R3(B3) D 402 Diode 1SS355 VR 401 Semi-fixed 3.3kΩ(OB) CCP1393 MIC 401 Microphone CPM1011 =====Circuit Symbol and No.===Part Name Part No. --- ------ ------------------------------------------ ------------------------- =====Circuit Symbol and No.===Part Name Part No. --- ------ ------------------------------------------ ------------------------- C www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 26 1 2 3 4 1 2 3 4 F E D C B A GM-8437ZT/WL RESISTORS R 401 RS1/16S222J R 402 RS1/16S683J R 403 RS1/16S103J R 404 RS1/16S472J R 405 RS1/16S471J R 406 RS1/16S271J R 407 RS1/16S684J R 408 RS1/16S682J R 409 RS1/16S472J R 410 RS1/16S472J R 411 RS1/16S473J R 412 RS1/16S153J R 413 RS1/16S153J R 414 RS1/16S101J R 417 RS1/16S1800D R 418 RS1/16S562J R 419 RS1/16S1002D R 420 RS1/16S2002D R 422 RS1/16S121J R 425 RS1/16S472J CAPACITORS C 401 CEJQ470M10 C 402 CEJQ470M10 C 403 CEALR68M50 C 404 CEJQ100M50 C 405 CEJQ470M10 C 406 CCSRCH101J50 C 407 CEJQ470M10 C 408 CEJQ100M50 C 409 CKSRYB473K25 C 410 CEJQNP220M10 C 411 CKSRYB104K16 C 412 CEJQNP100M16 C 413 CEJQNP4R7M16 C 414 CKSRYB103K50 C 415 CKSRYB223K50 C 416 CKSRYB474K10 Unit Number : CWM8256 Unit Name : Amp Assy MISCELLANEOUS IC 501 IC NJM4580MD IC 640 IC NJM4580MD IC 701 IC NJM4580MD IC 751 IC NJM4580MD IC 802 IC PAL006A IC 803 IC PAL006A IC 901 IC NJM2930F08K IC 902 IC BA178M05T IC 903 IC S-812C56AUA-C3K Q 601 Transistor 2SA1576 Q 621 Transistor 2SA1576 Q 631 Transistor 2SC4081 Q 632 Transistor 2SD1757K Q 633 Transistor DTC114EU Q 634 Transistor DTC114EU Q 802 Transistor DTA124EU Q 803 Transistor DTA124EU Q 831 Transistor 2SC4081 Q 832 Transistor 2SC4081 Q 833 Transistor 2SC4081 Q 901 Transistor 2SD1767 Q 902 Transistor 2SA1576 Q 903 Transistor 2SC4081 Q 904 Transistor 2SB1260 Q 905 Transistor DTA114EU Q 906 Transistor 2SB1260 Q 907 Transistor 2SA1587 Q 908 Transistor 2SC4081 Q 909 Transistor DTC144TU Q 913 Transistor DTC144EU Q 921 Transistor 2SC4081 Q 922 Transistor DTC144TU D 601 Diode 1SS355 D 621 Diode 1SS355 D 631 Diode HZU8R2(B3) D 632 Diode 1SS355 D 830 Diode UDZS7R5(B) D 901 Diode RM4LFJ10 D 902 Diode 1SS355 D 903 Diode MPG06G-6415G50 D 904 Diode UDZS16(B) D 905 Diode MPG06G-6415G50 D 907 Diode HZU3R3(B1) D 908 Diode MPG06G-6415G50 D 910 Diode 1SS355 D 921 Diode HZU8R2(B1) D 922 Diode HZU8R2(B2) D 951 Diode UDZS18(B) D 952 Diode UDZS18(B) L 901 Choke Coil 360µH CTH1268 RESISTORS R 501 RS1/16S1002D R 502 RS1/16S1002D R 503 RS1/16S1002D R 504 RS1/16S1002D R 505 RS1/16S3901D R 506 RS1/16S3901D R 507 RS1/16S3901D R 508 RS1/16S3901D R 509 RS1/16S4702D R 510 RS1/16S4702D R 511 RS1/16S4702D R 512 RS1/16S4702D R 513 RS1/16S4702D R 514 RS1/16S4702D R 515 RS1/16S4702D R 516 RS1/16S4702D R 517 RS1/16S101J R 518 RS1/16S101J R 601 RS1/16S912J R 602 RS1/16S472J R 621 RS1/16S912J R 622 RS1/16S472J R 631 RS1/16S104J R 632 RS1/16S473J R 633 RS1/16S222J R 634 RS1/16S103J R 635 RS1/16S103J R 636 RS1/16S333J R 637 RS1/16S272J R 638 RS1/16S333J R 640 RS1/16S5601D R 641 RS1/16S5601D R 644 RS1/16S1002D R 645 RS1/16S1002D R 648 RS1/16S1202D =====Circuit Symbol and No.===Part Name Part No. --- ------ ------------------------------------------ ------------------------- =====Circuit Symbol and No.===Part Name Part No. --- ------ ------------------------------------------ ------------------------- B www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 27 5 6 7 8 F E D C B A 5 6 7 8 GM-8437ZT/WL =====Circuit Symbol and No.===Part Name Part No. --- ------ ------------------------------------------ ------------------------- R 649 RS1/16S1202D R 652 RS1/16S2002D R 653 RS1/16S2002D R 654 RS1/16S101J R 703 RS1/16S822J R 704 RS1/16S822J R 705 RS1/16S303J R 706 RS1/16S303J R 707 RS1/16S223J R 708 RS1/16S223J R 709 RS1/16S123J R 710 RS1/16S123J R 719 RS1/16S201J R 721 RS1/16S474J R 722 RS1/16S474J R 725 RS1/16S101J R 726 RS1/16S101J R 731 RS1/16S912J R 732 RS1/16S912J R 733 RS1/16S101J R 734 RS1/16S101J R 751 RS1/16S101J R 752 RS1/16S912J R 753 RS1/16S822J R 756 RS1/16S223J R 758 RS1/16S223J R 760 RS1/16S103J R 762 RS1/16S101J R 803 RS1/16S184J R 804 RS1/16S184J R 832 RS1/16S271J R 833 RS1/16S271J R 835 RS1/16S472J R 836 RS1/16S472J R 837 RS1/8S272J R 838 RS1/16S182J R 839 RS1/16S183J R 901 RS1/8S472J R 902 RS1/8S222J R 903 RS1/16S182J R 904 RS1/16S562J R 905 RS1/16S471J R 908 RS1/16S473J R 909 RS1/16S103J R 910 RS1/10S331J R 911 RS1/16S103J R 912 RS1/10S561J R 914 RS1/16S121J R 915 RS1/16S101J R 916 RS1/10S121J R 917 RS1/10S151J R 920 RS1/10S121J R 921 RS1/10S151J R 923 RS1/16S362J R 924 RS1/16S473J R 925 RS1/16S104J R 926 RS1/16S473J R 927 RS1/16S104J R 935 RS1/16S183J R 936 RS1/16S103J R 939 RS1/16S432J R 940 RS1/16S512J R 951 RS1/4S101J R 952 RS1/4S101J CAPACITORS C 501 CEAT4R7M50 C 502 CEAT4R7M50 C 503 CEAT4R7M50 C 504 CEAT4R7M50 C 505 CCSRCH220J50 C 506 CCSRCH220J50 C 507 CKSRYB473K25 C 601 CKSQYB473K50 C 621 CKSQYB473K50 C 631 CEAT4R7M50 C 640 CEAT4R7M50 C 641 CEAT4R7M50 C 644 CCSRCH101J50 C 646 CKSRYB473K25 C 701 CCSRCH101J50 C 702 CCSRCH101J50 C 706 CKSRYB183K50 C 707 CKSRYB224K10 C 708 CKSRYB473K25 C 752 CKSRYB103K50 C 754 CKSRYB223K50 C 755 CKSRYB473K50 C 803 CFTNA224J50 C 804 CFTNA224J50 C 805 CFTNA224J50 C 806 CFTNA224J50 C 807 CFTNA224J50 C 808 CFTNA224J50 C 813 CFTNA224J50 C 814 CFTNA105J50 C 815 CFTNA105J50 C 816 CFTNA224J50 C 817 CEAT100M50 C 818 CEAT100M50 C 823 CKSQYB104K50 C 824 CEHAT221M25 C 825 CKSQYB104K25 C 826 CEHAT221M25 C 827 CKSQYB104K25 C 828 CKSQYB104K25 C 909 CKSRYB473K25 C 910 CEAT221M10 C 911 CKSRYB473K25 C 912 CEAT471M25 C 913 100µF/10V CCH1282 C 914 CKSRYB473K25 C 915 CKSRYB103K50 C 916 CKSRYB103K50 C 917 CKSQYB103K50 C 918 CKSQYB224K25 C 919 CKSQYB103K50 C 920 CKSQYB103K50 C 921 CEHAT331M10 C 922 100µF/10V CCH1282 C 923 100µF/10V CCH1282 C 924 100µF/10V CCH1282 C 925 CKSRYB104K16 C 928 CEAT3R3M50 C 931 6800µF/16V CCH1390 C 932 CEAT1R0M50 C 933 CEAT331M25 C 935 CEATR22M50 C 936 CEAT1R0M50 C 951 CKSQYB221K50 C 952 CKSQYB221K50 =====Circuit Symbol and No.===Part Name Part No. --- ------ ------------------------------------------ ------------------------- www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 28 1 2 3 4 1 2 3 4 F E D C B A GM-8437ZT/WL 6. ADJUSTMENT - Jigs When attaching the DSP unit to the Amp assy, use "Jigs" (GGD1245). GGD1245 =====Circuit Symbol and No.===Part Name Part No. --- ------ ------------------------------------------ ------------------------- C 953 CKSQYB221K50 C 954 CKSQYB221K50 C 955 CKSQYB221K50 C 956 CKSQYB221K50 C 957 CKSQYB221K50 C 958 CKSQYB221K50 C 961 CKSQYB332K50 C 962 CKSQYB332K50 C 963 CKSQYB332K50 C 964 CKSQYB332K50 C 965 CKSQYB332K50 C 966 CKSQYB332K50 C 967 CKSQYB332K50 C 968 CKSQYB332K50 C 969 CKSQYB332K50 C 970 CKSQYB332K50 C 971 CKSQYB332K50 C 972 CKSQYB332K50 C 973 CKSQYB332K50 C 974 CKSQYB332K50 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 29 5 6 7 8 F E D C B A 5 6 7 8 GM-8437ZT/WL H/U 12P 20P 20P AMP GM-8437ZT/WL 24P 20P GGD1373 24P 20P 20P Bullet connector (To DC Regulated Power Supply) FX-MG9327ZT/ES(R Handle) FX-MG9427ZT/ES(L Handle) - Connection Diagram www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 30 1 2 3 4 1 2 3 4 F E D C B A GM-8437ZT/WL 7. GENERAL INFORMATION 7.1 DIAGNOSIS 7.1.1 DISASSEMBLY 2 1 1 1 1 1 1 Fig.1 DSP Unit - Removing the Case (not shown) - Removing the DSP Unit (Fig.1) 1. Remove the two screws and then remove the Case. Remove the four screws and then remove the DSP Unit and the Shield Case together. Remove the solder and then straighten the tabs at seven locations indicated. 1 1 2 2 2 2 A DSP UNIT AMP ASSY A - Side View - Rear View Tweezers < Cautions and Techniques for removing the DSP Unit > There are some cautions and techniques for removing the DSP Unit. 1 Use a pair of tweezers as a lever. Insert the tips into the upper side-slits (A in Rear View) and get the bottom side of the Shield. Push the tweezers down in the direction indicated by an arrow in Side View. 2 Now one of the 18-pin connectors gets disconnected from the DSP Unit by doing 1 so that it becomes easier to detach the DSP Unit. Lift and remove the DSP Unit and the Shield together. Be careful not to give any stress to the 18-pin connectors on both sides when removing the DSP Unit and the Shield. Shield www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 31 5 6 7 8 F E D C B A 5 6 7 8 GM-8437ZT/WL - " Pawl bending and soldering " points of the pawls for securing the base plate of a shielded case (bot- tom case). The portion marked by is a point in which pawl bending. The portion marked by is a point in which pawl bending and soldering are necessary. Fig.2 3 3 3 3 1 1 1 1 1 1 2 Amp Assy Heat Sink 1 - Removing the Amp Assy (Fig.2) Remove the six screws and then remove the Heat Sink. 2 straighten the tab at location indicated. 3 Remove the four screws and then remove the Amp Assy. DSP UNIT www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 32 1 2 3 4 1 2 3 4 F E D C B A GM-8437ZT/WL 7.1.2 CONNECTOR FUNCTION DESCRIPTION ACC SPD INT1+ INT1- TX+ TX- (TXD+) (TXD-) SLD R+ (SLD) (R+) (R-) R- L+ (L+) (L-) L- (MUTE) MUTE FR- (SQR-) FR+ (SQR+) FL- (SQL-) FL+ (SQL+) RR- RR+ RL- RL+ GND GND2 WF1- (FWR-) WF1+ (FWR+) WF2- (FWL-) WF2+ (FWL+) CTR- CTR+ +B A B A B TMUT www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 33 5 6 7 8 F E D C B A 5 6 7 8 GM-8437ZT/WL If anything is wrong with IC301 or IC311 (AK7706VTA), DSP error will result. Under the occurrence of the error, DSP IC will be required to execute the initialization command by the system microcomputer until DSP IC gets back to normal. However, the error cannot be fixed because of defective IC, and so the initialization will be commanded over and over again. While this condition prevails, follow the description below about observations of the IC101 waveforms to distinguish defective DSP IC. [Observations of the IC101 waveforms] • First, perform the 67 pin (drst) waveform observations. When DSP error occurs, this waveform repeats "Hi/Low" shapes after ACC ON. For reference sake, when there is no problem, the 67 pin (drst) waveform should keep "Hi" continuously after ACC ON. • Then, perform the 19 pin (DSPCHIP) waveform observations. While the 67 pin (drst) waveform stays at "Low", perform the 19 pin waveform observations and produce a decision. • The 19 pin (DSPCHIP) waveform during DSP error Keeping "Hi" continuously : IC301 is defective. Proper IC311 operation is not guaranteed, though. After making repairs on IC301, re-perform the 67 pin (drst) waveform observations. Keeping "Hi" continuously on the 67 pin (drst) waveform shows that DSP IC functions normally. Keeping "Low" continuously : IC311 is defective. IC301 is OK. After making repairs on IC311, re-perform the 67 pin (drst) waveform observations. Keeping "Hi" continuously on the 67 pin (drst) waveform shows that DSP IC functions normally. - The 67 pin (drst) waveform during DSP error Hi(5V) Low(0V) 500ms The 19 pin (DSPCHIP) waveform 1 The waveform to indicate that IC301 is defective (No information about IC311) Hi(5V) Low(0V) Hi(5V) Low(0V) Hi(5V) Low(0V) 2 The waveform to indicate that IC311 is defective - The 67 pin (drst) waveform during normal DSP operation [Observations of the IC101 waveform (for drst and DSPCHIP)] 7.1.3 THE METHOD OF DISTINGUISHING DEFECTIVE DSP IC (IC301 OR IC311) DURING DSP ERROR www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 34 1 2 3 4 1 2 3 4 F E D C B A GM-8437ZT/WL CN102 CN101 IC101 19pin DSPCHIP 67pin drst TEST DSP UNIT SIDE A www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 35 5 6 7 8 F E D C B A 5 6 7 8 GM-8437ZT/WL - Pin Functions (PD5769B) Pin No. Pin Name I/O Function and Operation 1 DSPCK1 O DSP 1 I/F serial clock output 2 VCS2 O Electronic volume 2 strobe output 3 VCS1 O Electronic volume 1 strobe output 4 VDT O Electronic volume serial data output 5 VCK O Electronic volume serial clock output 6 CNVSS Connect to GND 7 MODEL0 I Model information input 8 PDN O DAC power down output 9 reset I Reset input 10 XOUT O System clock output 11 VSS GND 12 XIN I System clock input (10MHz) 13 VCC Power supply (+5V) 14 nmi I Connect to VCC 15 SPEED I Speed sensor pulse input 16 bsens I Backup sense input 17 asens I ACC sense input 18 AVCINT I AVC-LAN data input 19 DSPCHIP O DSP error output 20 AVCPW O AVC-LAN driver power output 21 BEEP O Beep pulse output 22 AVCIN I AVC-LAN data input 23 AVCOUT O AVC-LAN data output 24 DSPOUT2 O DSP 2 I/F serial data output 25 DSPIN2 I DSP 2 I/F serial data input 26 DSPCK2 O DSP 2 I/F serial clock output 27 TESTIN I Test program input 28 TSOUT O Test serial data output 29 TSIN I Test serial data input 30 TSCK I Test serial clock input 31 SMUTEIN I System mute input 32 DACCSN O DAC control chip select output 33 DACCCLK O DAC control clock output 34 DACCDTI O DAC control data output 35 NC Not used 36 TELMUTE I TEL mute input 37,38 NC Not used 39 ROMDT I ROM correction data input 40 MUTE O System mute output 41,42 NC Not used 43 FRMUTE O Interrupt signal FR SP mute 44 FLMUTE O Interrupt signal FL SP mute 45 RRMUTE O Interrupt signal RR SP mute 46 RLMUTE O Interrupt signal RL SP mute 47 CTRMUTE O Interrupt signal CTR SP mute 48 WFMUTE O Interrupt signal WF SP mute 49-52 NC Not used 53 FRINT2 O Interrupt signal H:INT(FR) L:OFF 54 FRINT1 O Interrupt signal H:FR L:OFF 55 FLINT2 O Interrupt signal H:INT(FL) L:OFF 56 FLINT1 O Interrupt signal H:FL L:OFF 57 RRINT2 O Interrupt signal H:INT(RR) L:OFF 58 RRINT1 O Interrupt signal H:RR L:OFF 59 RLINT2 O Interrupt signal H:INT(RL) L:OFF 60 RLINT1 O Interrupt signal H:RL L:OFF 61 CTRINT2 O Interrupt signal H:INT(CTR) L:OFF 62 CTRINT1 O Interrupt signal H:CTR L:OFF 63 dirst O DSP reset output 7.2 IC www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 36 1 2 3 4 1 2 3 4 F E D C B A GM-8437ZT/WL * PD5769B 20 21 40 41 60 61 80 1 IC's marked by * are MOS type. Be careful in handling them because they are very liable to be damaged by electrostatic induction. Pin No. Pin Name I/O Function and Operation 64 calib O Power IC control output 65 PWSENS I Power IC heat sense input 66 SYSPW O System power output 67 drst O DSP reset output (DSP) 68 drq2 O DSP 2 request output 69 DSDRDY2 I DSP 2 data ready input 70 RDY2 I DSP 2 write in ready input 71 drq1 O DSP 1 request output 72 DSDRDY1 I DSP 1 data ready input 73 RDY1 I DSP 1 write in ready input 74 ASLIN I ASL noise input 75 AVSS GND for microcomputer AD 76 SMUTE O DSP soft mute output 77 VREF Reference for microcomputer AD 78 AVCC Power supply for microcomputer AD 79 DSPIN1 I DSP 1 I/F serial data input 80 DSPOUT1 O DSP 1 I/F serial data output www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 37 5 6 7 8 F E D C B A 5 6 7 8 GM-8437ZT/WL VREF 1 2 3 VDD VSS OUT S-80835CNUA-B8U 1 2 3 VIN VOUT GND Reference Voltage S-812C56AUA-C3K 1 3 2 A OUTPUT A -INPUT A +INPUT V- B +INPUT B -INPUT B OUTPUT V+ 4 5 6 7 8 + + A B NJM4580MD A0-A16 ce oe we I/O0-I/O7 VCC GND :Address input :Chip enable input :Output enable input :Write enable input :Input / Output :Power :GND 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 A11 A9 A8 A13 we CE2 A15 VCC NC A16 A14 A12 A7 A6 A5 A4 32 31 30 29 28 17 16 15 14 13 22 21 20 19 18 17 oe A10 ce1 I/O7 I/O6 I/O5 I/O4 I/O3 GND I/O2 I/O1 I/O0 A0 A1 A2 A3 IC62C1024AL-70TI www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 38 1 2 3 4 1 2 3 4 F E D C B A GM-8437ZT/WL - Pin Functions (AK7706VTA) Pin No. Pin Name I/O Function and Operation 1 SDOUT1 O DSP serial data output pin 2 SDOUT2 O DSP serial data output pin 3 SDOUT3 O DSP serial data output pin 4 SDOUT4 O DSP serial data output pin 5 DVDD Digital : Power supply pin (5V or 3.3V) 6 DVSS Digital : GND pin (0V) 7 SDIN1 I DSP serial data input pin 8 SDIN2 I DSP serial data input pin 9 SDIN3 I DSP serial data input pin 10 LRCLK I/O L / R channel select pin 11 BITCLK I/O Serial bit clock pin 12 CLKO O Clock output pin 13 CTRL Clock output control pin 14 DVDD Digital : Power supply pin (5V or 3.3V) 15 DVSS Digital : GND pin (0V) 16 XTI I Master clock input pin 17 XTO O Crystal oscillator output pin 18 TESTI1 Test pin 19 INIT_RESET I Reset pin 20 DSP_RESET I Reset pin 21 SMODE I Slave / Master mode select pin 22 JX I Outside condition pin 23 rq I Request pin for microcomputer interface 24 SCLK I Serial data clock input pin for microcomputer interface 25 SI I Serial data input / Serial data output control pin for microcomputer interface 26 DVSS Digital : GND pin (0V) 27 DVDD Digital : Power supply pin (5V) 28 SO O Serial data output pin for microcomputer interface 29 RDY O Data write in ready output pin for microcomputer interface 30 DRDY O Output data ready for microcomputer interface 31 LSEL I Input pin select pin 32 cas O Option DRAM : cas pin 33 ras O Option DRAM : ras pin 34 we O Outside SRAM / DRAM : Write enable pin 35-39 A0-4 O Outside RAM : Address output pin 40 DVSS Digital : GND pin (0V) 41 DVDD Digital : Power supply pin (5V or 3.3V) 42-53 A5-16 O Outside RAM : Address output pin 54 DVDD Digital : Power supply pin (5V or 3.3V) 55 DVSS Digital : GND pin (0V) 56 oe O Outside RAM : Output enable pin 57-64 IO0-7 I/O Outside RAM : Data input / output pin 16 17 32 33 48 49 64 1 * AK7706VTA www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 39 5 6 7 8 F E D C B A 5 6 7 8 GM-8437ZT/WL - Pin Functions (AK4529XQ) Pin No. Pin Name I/O Function and Operation 1 SDOS I SDTO source select pin 2 I2C I Serial control mode select pin 3 SMUTE I Soft mute pin 4 BICK I Audio serial data clock pin 5 LRCK I Input channel clock pin 6 SDTI1 I DAC1 audio serial data input pin 7 SDTI2 I DAC2 audio serial data input pin 8 SDTI3 I DAC3 audio serial data input pin 9 SDTO O Audio serial data output pin 10 DAUX I Assistance audio serial data input pin 11 DFS I Double speed sampling mode pin 12 SDTI4 I DAC4 audio serial data input pin 13 DZFE I 0 input detect pin 14 TVDD Power supply for output buffer 15 DVDD Digital : Power supply pin 16 DVSS Digital : GND pin (0V) 17 PDN I Power down and reset pin 18 TST I Test pin 19 CAD1 I Chip address 1 pin 20 CAD0 I Chip address 0 pin 21 LOUT4 O DAC4 L channel analog output pin 22 ROUT4 O DAC4 R channel analog output pin 23 LOUT3 O DAC3 L channel analog output pin 24 ROUT3 O DAC3 R channel analog output pin 25 LOUT2 O DAC2 L channel analog output pin 26 ROUT2 O DAC2 R channel analog output pin 27 LOUT1 O DAC1 L channel analog output pin 28 ROUT1 O DAC1 R channel analog output pin 29,30 NC Not used 31 LIN I L channel analog input pin 32 RIN I R channel analog input pin 33 DZF2 O 0 input detect pin 34 VCOM O Common voltage output pin 35 VREFH I Reference voltage input pin 36 AVDD Analog power supply pin 37 AVSS Analog GND pin 38 DZF1 O 0 input detect pin 39 MCLK I Master clock input pin 40 P/S I Parallel / Serial select pin 41 DIF0/CSN I Audio interface format 0 pin / Chip select pin 42 DIF1/CCLK I Audio interface format 1 pin / Control data clock pin 43 LOOP0/CDTI I/O Loop back mode 0 pin / Control data input pin 44 TDM I TDM I/F format mode pin 11 12 22 23 33 34 44 1 * AK4529XQ www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 40 1 2 3 4 1 2 3 4 F E D C B A GM-8437ZT/WL AUDIO H/U (OTHER MAKERS) GM-8437ZT/WL POWER AMPLIFIER EMV-N (CD, MD) CHANGER (OTHER MAKERS) (OTHER MAKERS) +B, ACC - EMV-N • RSE(EGA • VGA) POWER SUPPLY(+B, ACC) BUS SIGNAL(SOUND, VISION) SIGNAL(2) RSE (OTHER MAKERS) TV TUNER (OTHER MAKERS) VTR ADAPTER (OTHER MAKERS) ECU (OTHER MAKERS) AUDIO H/U (OTHER MAKERS) GM-8437ZT/WL POWER AMPLIFIER EMV-N (CD, MD) CHANGER (OTHER MAKERS) (OTHER MAKERS) +B, ACC - EMV-N (EGA • VGA) ECU (OTHER MAKERS) MIC SOUND VOICE INTERRUPT MIC SOUND VOICE INTERRUPT AUDIO H/U (OTHER MAKERS) GM-8437ZT/WL POWER AMPLIFIER INTEGRATED PANEL (CD, MD) CHANGER (OTHER MAKERS) (OTHER MAKERS) +B, ACC - AUDIO (INTEGRATED PANEL) ECU (OTHER MAKERS) VOICE INTERRUPT MIC SOUND 7.3 EXPLANATION 7.3.1 SYSTEM BLOCK DIAGRAM www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 41 5 6 7 8 F E D C B A 5 6 7 8 GM-8437ZT/WL 8. OPERATIONS There is no information to be shown in this chapter. 7.3.2 OPERATIONAL FLOW CHART Reset Start---OFF ---Power ON <> Test program check(Unit checker) - Pin 27 HI/LOW input Unit checker program Pin 27 HI input Pin 27 LOW input <> Back up, ACC confirmation - Pin 17 ACC/Pin 16 Back up Microcomputer oscillation stop (Electronic power save) Pin 17 LOW input and Pin 16 LOW input • ACC/Back up ON Main loop <> Bus communication Normal/Error <> System ON/OFF - OFF status =System ON waiting • Power ON(Pin 66 H) • Mute ON(Pin 40 H) • BEEP output available - ON status =System OFF waiting • Power ON(Pin 66 H) • Mute OFF(Pin 40 L) • BEEP output available <> DSP error confirmation • communication error:Serial IF <> ACC/Back up ON/OFF START | Hard ware reset cancel Main loop Error retry • DSP reset(Pin 67) | About 1 second Error(Communication error) | Forcibly OFF Pin 17 HI input or Pin 16 HI input Normal(Main unit communication normal) OFF ON Normal operation DSP error ACC ON/Back up ON Pin 17 HI input or Pin 16 HI input Pin 17 LOW input and Pin 16 LOW input www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 42 1 2 3 4 1 2 3 4 F E D C B A GM-8437ZT/WL - Jigs List Name Jig No. Remarks S/M Location 18P Extension Cord GGD1245 For the extension between Amp Board and DSP Board. P.28 03 CROWN GGD1373 For system connection of Amp Unit and Head Unit. P.29 Amp System Cord Head Unit FX-MG9327ZT/ES or For operation and confirmation of Amp. P.29 FX-MG9427ZT/ES www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com
