PIONEER ELECTRONIC CORPORATION 4-1, Meguro 1-Chome, Meguro-ku, Tokyo 153-8654, Japan PIONEER ELECTRONICS SERVICE INC. P.O.Box 1760, Long Beach, CA 90801-1760 U.S.A. PIONEER ELECTRONIC [EUROPE] N.V. Haven 1087 Keetberglaan 1, 9120 Melsele, Belgium PIONEER ELECTRONICS ASIACENTRE PTE.LTD. 501 Orchard Road, #10-00, Wheelock Place, Singapore 238880 C PIONEER ELECTRONIC CORPORATION 1998 K-FED. APR. 1998 Printed in Japan ORDER NO. CRT2181 RECEIVER ASSY RADIO Service Manual FH-2816ZF X1H/UC FH-2716ZF X1H/UC NOTE: - Dolby noise reduction manufactured under license from Dolby Laboratories Licensing Corporation. "Dolby" and the double-D symbol are trademarks of Dolby Laboratories Licensing Corporation. - See the separate manual CX-631(CRT1640) for the cassette mechanism description. - The cassette mechanism assy employed in this model is one of 2L series - See the separate manual CX-597(CRT1829) for the CD mechanism description, disassembly and circuit description. - The CD mechanism employed in this model is one of S7 series. CONTENTS 1. SAFETY INFORMATION ...........................................2 2. EXPLODED VIEWS AND PARTS LIST......................3 3. SCHEMATIC DIAGRAM ..........................................10 4. PCB CONNECTION DIAGRAM ...............................42 5. ELECTRICAL PARTS LIST .......................................58 6. ADJUSTMENT ........................................................76 7. GENERAL INFORMATION ......................................81 7.1 PARTS.................................................................81 7.1.1 IC ...............................................................81 7.1.2 DISPLAY ...................................................78 7.2 DIAGNOSIS........................................................89 7.2.1 FUNCTION................................................89 7.2.2 DISASSEMBLY.........................................90 7.2.3 TEST MODE .............................................92 7.2.4 CONNECTOR FUNCTION DESCRIPTION..96 7.3 BLOCK DIAGRAM..............................................98 8. OPERATIONS AND SPECIFICATIONS .................100 FORD FH-2816ZF/X1H/UC VEHICLE DESTINATION PRODUCED AFTER FORD PART No. ID No. PIONEER MODEL No. Nissan Quest U.S.A. CANADA April 1998 XF5F-18C868-DB - FH-2816ZF/X1H/UC Ford Villager U.S.A. CANADA April 1998 XF5F-18C868-CB - FH-2716ZF/X1H/UC www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 2 FH-2816ZF,2716ZF 1. SAFETY INFORMATION CAUTION This service manual is intended for qualified service technicians; it is not meant for the casual do-it-yourselfer. Qualified technicians have the necessary test equipment and tools, and have been trained to properly and safely repair complex products such as those covered by this manual. Improperly performed repairs can adversely affect the safety and reliability of the product and may void the warranty. If you are not qualified to perform the repair of this product properly and safely, you should not risk trying to do so and refer the repair to a qualified service technician. WARNING Lead in solder used in this product is listed by the California Health and Welfare agency as a known reproductive toxicant which may cause birth defects or other reproductive harm (California Health and Safety Code, Section 25249.5). When servicing or handling circuit boards and other components which contain lead in solder, avoid unprotected skin contact with the solder. Also, when soldering do not inhale any smoke or fumes produced. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 5 3 3 3 3 4 4 4 4 2 6 2 1 3 FH-2816ZF,2716ZF 2. EXPLODED VIEWS AND PARTS LIST 2.1 PACKING 1 Contain Box HHL0107 2 Protector HHP0013 3 Protector HHP0014 4 Protector HHP0015 * 5 Cover HHP0027 6 LID HHW0005 NOTE: - Parts marked by “*”are generally unavailable because they are not in our Master Spare Parts List. - Screws adjacent to Ñ mark on the product are used for disassembly. Mark No. Description Part No. - PACKING SECTION PARTS LIST www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 4 FH-2816ZF,2716ZF 2.2 EXTERIOR www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 5 FH-2816ZF,2716ZF 1 Screw BMZ26P250FMC 2 Screw BSZ26P050FMC 3 Screw BSZ30P050FMC 4 Screw BSZ30P120FMC 5 Connector CDE5462 6 CD Mechanism Module CXK5028 7 Transistor(Q1054) 2SD2396 8 IC(IC802) PA2024A 9 Transistor(Q805) 2SA1358 10 Transistor(Q803) 2SA1358 11 Cassette Mechanism Module EXK3285 12 Screw HBA1416 13 Cord HDE5049 14 IC(IC301) TDA7384 15 Holder HNC6654 16 Spacer HNM4761 17 Knob Assy HXA9429 18 Connector(CN955) HKS3128 19 Connector(CN956) HKS3128 20 Connector(CN954) HKS3129 21 Case HNB2059 22 Insulator HNM4745 * 23 Insulator HNM5230 24 Seal HNM5701 25 Heat Sink HNR1418 26 Mother Unit See Contrast table (2) 27 Screw BMZ26P060FMC 28 Screw See Contrast table (2) * 29 Cord CDE5451 30 Plug(CN952) CKS3537 31 Plug(CN953) CKS3538 32 Spacer CNM5859 33 Tuner Unit CWE1428 34 Holder CNC6122 35 Connector(CN702) HKS1730 36 Connector(CN701) HKS2256 37 Antenna Jack(CN402) HKX1054 38 Antenna Jack(CN401) See Contrast table (2) 39 Holder HNC6458 * 40 Holder See Contrast table (2) * 41 Insulator HNM5228 42 Compound Unit HWM5956 43 Screw BMZ26P060FMC 44 Plug(CN1001) CKS1621 45 Plug(CN201) CKS1622 46 Connector(CN901) HKM1237 47 Connector(CN1051) HKS3129 * 48 Holder HNC6457 49 Holder HNC6470 50 Holder HNC6650 51 Shield HNC6930 * 52 Insulator HNM5229 53 Chassis Unit HXA8842 54 Chassis Unit HXB2066 55 Screw BPZ26P080FMC 56 Sheet CNM5480 * 57 Duble Side Sheel CNM5582 58 Grille Unit CXB2065 59 Cord HDE4949 60 Shield HNC7337 61 Conductor HNC7688 62 Conductor HNC7689 63 Rubber HNV4541 64 Keyboard Unit HWM6008 65 Socket(CN958) CKS3550 66 Socket(CN957) CKS3551 67 VF HAW1359 Mark No. Description Part No. Mark No. Description Part No. (1)EXTERIOR SECTION PARTS LIST (2) CONTRAST TABLE FH-2816ZF/X1H/UC and FH-2716ZF/X1H/UC are constructed the same except for the following: Part No. Mark No. Description FH-2816ZF/X1H/UC FH-2716ZF/X1H/UC 26 Mother Unit HWM5106 HWM5104 38 Antenna Jack(CN401) HKX1055 Not used * 40 Holder HNC6651 HNC6459 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 6 FH-2816ZF,2716ZF 2.3 CD MECHANISM MODULE www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 7 FH-2816ZF,2716ZF 1 Control Unit CWX2249 2 Pickup Unit (Service) CXX1232 3 Screw IMS26P035FMC 4 Screw BMZ20P025FMC 5 Screw BMZ20P040FMC 6 Screw BSZ20P040FMC 7 Screw (M2´3) CBA1077 8 Screw (M2´2) CBA1250 9 Screw (M2´5) CBA1296 10 Screw (M2´3.85) CBA1362 11 Spring CBH1724 12 Spring CBH1729 13 Spring CBH1730 14 Spring CBH1731 15 Spring CBH1732 16 Spring CBH1745 17 Spring CBH1848 18 Spring CBH1849 19 Spring CBH1939 20 Spring CBL1214 21 Roller CLA2627 22 Frame CNC6670 23 Bracket CNC5871 * 24 Bracket CNC6376 25 Cushion CNM3917 26 Sheet CNM4873 27 ••••• 28 Gathering PCB CNX2977 29 Bearing CNR1415 30 Belt CNT1071 31 Damper CNV3974 32 Gear CNV4128 33 Gear CNV4129 34 Gear CNV4857 35 Gear CNV4131 36 Holder CNV4663 37 Holder CNV5071 38 Guide CNV4484 39 Screw Unit CXA8699 40 CRG Motor Unit (M2) CXA8986 41 Motor Unit (M1) CXA9101 42 Lever Unit CXA9300 43 Chassis Unit CXB2574 44 Screw JGZ17P025FZK 45 Connector (CN101) CKS1953 46 Connector (CN701) CKS2775 47 Connector (CN801) CKS2196 48 Spring CBH1832 49 Spring CBH1833 50 Roller CLA2627 51 Arm CNV4136 52 Arm Unit CXA8565 53 Bracket CNC6056 54 Load Motor Unit (M3) CXA8702 55 Screw JFZ20P025FMC 56 Arm CNV4120 57 Roller CNV4509 58 Gear Unit CXA8701 59 Screw (M2´ 5) CBA1296 60 Frame CNC6844 61 Damper CNV3974 62 Spring CBH1736 63 Spring CBH1863 64 Spring CBH1945 65 Spring CBL1269 66 Arm CNC5799 67 Lever CNC6054 68 Spacer CNM3315 69 Sheet CNM4849 70 Arm CNV4122 71 Arm CNV4123 72 Arm CNV4124 73 Arm CNV4125 74 Arm CNV4138 75 Arm CNV4139 76 Clamper CNV4140 77 Screw (M2´2) CBA1250 78 Connector CDE4576 79 Arm CNC7383 * 80 Gathering PCB CNX2445 81 Photo-transistor (Q1, 2) CPT-230S-X 82 Frame Assy CXB1068 83 Elbo Arm Assy CXA8889 84 Load Motor Assy CXA8891 85 LO Arm Assy CXA8892 86 Shaft CLA3133 87 Guide Arm Assy CXB1850 Mark No. Description Part No. Mark No. Description Part No. - CD MECHANISM MODULE SECTION PARTS LIST www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 8 FH-2816ZF,2716ZF 2.4 CASSETTE MECHANISM MODULE www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 9 FH-2816ZF,2716ZF 1 Screw BSZ20P040FMC 2 Washer CBF1037 3 Washer CBF1038 4 Washer CBG1003 5 Deck Unit EWM1007 6 Screw (M2´5) EBA1028 7 Screw (M2´2.5) EBA1037 8 Spring EBH1531 9 Spring EBH1589 10 Cushion ENM1034 11 Spring EBH1515 12 Spring EBH1587 13 Spring EBH1517 14 Spring EBH1518 15 Spring EBH1519 16 Spring EBH1537 17 Cord EDD1015 18 Photo-reflector (EGN2, 3) EGN1004 19 Photo-interrupter (EGN1) EGN1005 20 Roller ENR1031 21 Shaft ELA1362 22 Roller ELA1348 23 Arm ENC1396 24 Arm ENC1397 25 Guide ENC1398 26 Holder ENC1417 27 Lever ENC1448 28 Arm ENC1401 29 Roller ENR1027 30 Belt ENT1027 31 Gear ENV1347 32 Collar ENV1508 33 Gear ENV1350 34 Flywheel ENV1410 35 Worm Gear ENV1439 36 Worm Wheel ENV1440 37 Gear ENR1028 38 Lever ENV1442 39 Arm ENV1445 40 Gathering PCB ENX1029 41 Gathering PCB ENX1041 42 Switch (S1) ESG1004 43 Motor Unit(M2) EXA1382 44 Chassis Unit EXA1495 45 Pinch Roller Unit EXA1472 46 Pinch Roller Unit EXA1473 47 Reel Unit EXA1484 48 Head Base Unit EXA1434 49 Lever Unit EXA1438 50 Gear Unit EXA1436 51 Frame Unit EXA1476 52 Lever Unit EXA1439 53 Head Assy(HD1) EXA1488 54 Motor Unit (M1) EXA1381 55 Washer HBF-179 56 Screw JGZ20P025FNI 57 Resistor (R1) RD1/4HM181J 58 Washer YE20FUC 59 Connector (CN251) CKS1711 60 Connector (CN252) CKS2127 61 Connector (CN253) CKS2129 62 ••••• 63 Spring EBH1545 64 Switch (S2) ESG1004 65 Roller ENR1023 66 Cover ENC1412 67 Cover ENC1413 68 Inductor (L1) ETH0001 69 Capacitor (C1) CEAL4R7M35LS2 Mark No. Description Part No. Mark No. Description Part No. - CASSETTE MECHANISM MODULE SECTION PARTS LIST www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com % % 10 1 2 3 4 1 2 3 4 D C B A FH-2816ZF,2716ZF 3. SCHEMATIC DIAGRAM 3.1 OVERALL CONNECTION DIAGRAM (GUIDE PAGE) (FH-2816ZF/X1H/UC) Note: When ordering service parts, be sure to refer to “EXPLODED VIEWS AND PARTS LIST” or “ELECTRICAL PARTS LIST”. A-a A-b A-a A-a A-b A-b A-b A-b A-a A-a Large size SCH diagram Guide page Detailed page A-a A www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 11 FH-2816ZF,2716ZF 5 6 7 8 5 6 7 8 D C B A A A-b www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 12 1 2 3 4 1 2 3 4 D C B A FH-2816ZF,2716ZF A-a A-a A-b % % www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 13 FH-2816ZF,2716ZF 5 6 7 8 5 6 7 8 D C B A A-a A-a A-b www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 14 1 2 3 4 1 2 3 4 D C B A FH-2816ZF,2716ZF A-a A-b A-b C189 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 15 FH-2816ZF,2716ZF 5 6 7 8 5 6 7 8 D C B A A-b A-a A-b www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com % 16 1 2 3 4 1 2 3 4 D C B A FH-2816ZF,2716ZF 3.2 OVERALL CONNECTION DIAGRAM (GUIDE PAGE) (FH-2716ZF/X1H/UC) A-a A-b A-a A-a A-b A-b A-b A-b A-a A-a Large size SCH diagram Guide page Detailed page A-a A www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 17 FH-2816ZF,2716ZF 5 6 7 8 5 6 7 8 D C B A A-b A www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 18 1 2 3 4 1 2 3 4 D C B A FH-2816ZF,2716ZF A-a % % A-a A-b www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 19 FH-2816ZF,2716ZF 5 6 7 8 5 6 7 8 D C B A A-a A-a A-b www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 20 1 2 3 4 1 2 3 4 D C B A FH-2816ZF,2716ZF A-a A-b A-b www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 21 FH-2816ZF,2716ZF 5 6 7 8 5 6 7 8 D C B A A-b A-a A-b www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 22 1 2 3 4 1 2 3 4 D C B A FH-2816ZF,2716ZF G H 3.3 CD MECHANISM MODULE G-a G H A-a A-a A-b A-b A-a A-b A-b A-a Large size SCH diagram Guide page Detailed page www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 23 FH-2816ZF,2716ZF 5 6 7 8 5 6 7 8 D C B A A G-b G www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 24 1 2 3 4 1 2 3 4 D C B A FH-2816ZF,2716ZF G G-a G-b G-a www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 25 FH-2816ZF,2716ZF 5 6 7 8 5 6 7 8 D C B A H G-a G-b G-a H www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 26 1 2 3 4 1 2 3 4 D C B A FH-2816ZF,2716ZF G-a G-b G-b www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 27 FH-2816ZF,2716ZF 5 6 7 8 5 6 7 8 D C B A A G-a G-b G-b www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 28 FH-2816ZF,2716ZF 1 RFO 0.5V/div. 0.5µs/div. Normal mode: play 1 CH1: RFO 1V/div. 2 CH2: MIRR 5V/div. Test mode: Tracking open 0.5ms/div. 1 CH1: RFO 1V/div. 2 CH2: MIRR 5V/div. Normal mode: The defect part passes 800µm 0.5ms/div. 3 CH1: FIN 0.5V/div. 4 CH2: FO+ 2V/div. Test mode: No disc, Focus close 0.2s/div. 3 CH1: FIN 0.5V/div. 5 CH2: FOK 2V/div. Normal mode: Focus close 0.2s/div. 6 CH1: FEY 0.5V/div. 7 CH2: XSI 2V/div. Normal mode: Focus close 1ms/div. REFO ® 8 CH1: TEY 0.5V/div. 9 CH2: TIN 0.5V/div. Test mode: 32 tracks jump (FWD) 0.5ms/div. 8 CH1: TEY 0.5V/div. 9 CH2: TIN 0.5V/div. Test mode: Single jump (FWD) 0.5ms/div. 8 CH1: TEY 0.5V/div. 9 CH2: TIN 0.5V/div. Test mode: 100 tracks jump (FWD) 5ms/div. 6 CH1: FEY 0.1V/div. 3 CH2: FIN 0.2V/div. Normal mode: Play 20ms/div. 3 CH1: FIN 0.5V/div. 0 CH2: SIN 1V/div. Normal mode: Focus close (12cm) 0.5s/div. 3 CH1: FIN 0.5V/div. 0 CH2: SIN 1V/div. Normal mode: Focus close (8cm) 0.5s/div. GND ® GND ® REFO ® REFO ® REFO ® REFO ® GND ® REFO ® REFO ® GND ® REFO ® REFO ® REFO ® REFO ® REFO ® REFO ® REFO ® REFO ® REFO ® REFO ® REFO ® REFO ® - Waveforms Note:1. The encircled numbers denote measuring pointes in the circuit diagram. 2. Reference voltage REFO:2.5V www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 29 FH-2816ZF,2716ZF 8 CH1: TEY 0.2V/div. 9 CH2: TIN 0.2V/div. Normal mode: play 8 CH1: TEY 0.5V/div. ! CH2: SD 0.5V/div. 5ms/div. 0 SIN 0.5V/div. 0.1s/div. Normal mode: Play (12cm) 0 SIN 0.5V/div. 10ms/div. Long Search (12cm) @ EFM 1V/div. 5µs/div. Play 8 CH1: TEY 1V/div. # CH2: TEC 1V/div. Test mode: Focus close Tracking open 2ms/div. 8 CH1: TEY 0.5V/div. 6 CH2: FEY 0.5V/div. Normal mode: AGC after focus close 0.2s/div. $ PLCK 2V/div. 0.5µs/div. Play 20ms/div. % SCKO 2V/div. 1µs/div. Play ^ Dout 2V/div. 10µs/div. Play & LRCK 2V/div. 20µs/div. * VD 5V/div. 50ms/div. Normal mode: No disc GND ® REFO ® REFO ® GND ® REFO ® REFO ® REFO ® REFO ® REFO ® REFO ® REFO ® REFO ® REFO ® GND ® REFO ® GND ® REFO ® GND ® REFO ® GND ® REFO ® www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 30 FH-2816ZF,2716ZF ( CH1: R OUT 1V/div. ) CH2: L OUT 1V/div. Normal mode: Play (1kHz 0dB) 6 CH1: FEY 0.2V/div. 3 CH2: FIN 0.5V/div. Normal mode: During AGC 1ms/div. 8 CH1: TEY 0.2V/div. 9 CH2: TIN 0.5V/div. Normal mode: During AGC 1 CH1: RFO 1V/div. ⁄ CH2: HOLD 5V/div. Normal mode: The defect part passes 800µm 0.2ms/div. 1ms/div. 0.5ms/div. 3 CH1: FIN 1V/div. ⁄ CH2: HOLD 5V/div. Normal mode: The defect part passes 800µm 0.5ms/div. GND ® GND ® REFO ® REFO ® REFO ® REFO ® REFO ® REFO ® www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com FH-2816ZF,2716ZF 31 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 32 1 2 3 4 1 2 3 4 D C B A FH-2816ZF,2716ZF 3.4 TUNER UNIT A B B www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 33 FH-2816ZF,2716ZF 5 6 7 8 5 6 7 8 D C B A B www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com C A F L 34 1 2 3 4 1 2 3 4 D C B A FH-2816ZF,2716ZF 3.5 KEYBOARD UNIT C L www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 35 FH-2816ZF,2716ZF 5 6 7 8 5 6 7 8 D C B A A C www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 36 1 2 3 4 1 2 3 4 D C B A FH-2816ZF,2716ZF 3.6 EQ PCB D www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 37 FH-2816ZF,2716ZF 5 6 7 8 5 6 7 8 D C B A D www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 38 1 2 3 4 1 2 3 4 D C B A FH-2816ZF,2716ZF E A 3.7 CONNECTOR PCB E www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 39 FH-2816ZF,2716ZF 1 2 3 4 1 2 3 4 D C B A F C ERA83-006 SC016-2 3.8 VF SUB PCB F www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 40 1 2 3 4 1 2 3 4 D C B A FH-2816ZF,2716ZF 3.9 CASSETTE MECHANISM MODULE I A I www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 41 FH-2816ZF,2716ZF 5 6 7 8 5 6 7 8 D C B A J K J K I www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 42 1 2 3 4 1 2 3 4 D C B A FH-2816ZF,2716ZF 1 9 2 10 3 11 4 12 5 13 6 14 18 24 19 25 20 26 21 27 22 28 23 29 7 15 8 16 17 31 32 33 34 35 36 30 NOTE FOR PCB DIAGRAMS 1. The parts mounted on this PCB include all necessary parts for several destination. For further information for respective destinations, be sure to check with the schematic diagram. 2. Viewpoint of PCB diagrams 4. PCB CONNECTION DIAGRAM 4.1 MOTHER UNIT Capacitor Connector P.C.Board Chip Part SIDE A SIDE B A A MOTHER UNIT E CN1001 G CN701 C CN958 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com SUB ANTENNA MAIN ANTENNA 43 FH-2816ZF,2716ZF 5 6 7 8 5 6 7 8 D C B A A SIDE A C CN201 C CN251 I C CN957 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 44 1 2 3 4 1 2 3 4 D C B A FH-2816ZF,2716ZF A A MOTHER UNIT www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 45 FH-2816ZF,2716ZF 5 6 7 8 5 6 7 8 D C B A SIDE B A www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 46 1 2 3 4 1 2 3 4 D C B A FH-2816ZF,2716ZF 4.2 CD MECHANISM MODULE SIDE A G CONTROL UNIT G CN701 A SERVICE PICKUP UNIT www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 47 FH-2816ZF,2716ZF 1 2 3 4 1 2 3 4 D C B A M HOME CLAMP M 4 5 6 7 3 2 1 M1 SPINDLE MOTOR M2 CARRIAGE MOTOR SIDE B H G H PHOTO UNIT CONTROL UNIT CN801 G G H www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 48 1 2 3 4 1 2 3 4 D C B A FH-2816ZF,2716ZF 4.3 TUNER UNIT SIDE A B TUNER UNIT B A www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 49 FH-2816ZF,2716ZF 1 2 3 4 1 2 3 4 D C B A 1 2 3 5 4 SIDE B B TUNER UNIT B www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 50 1 2 3 4 1 2 3 4 D C B A FH-2816ZF,2716ZF AM FM TUNE> 1/REW SCAN 2/FF AM BASS TERB 3/SIDE1-2 TAPE EJECT BAL FAD RDS CD AUTO PHONE TAPE CD EJECT 4.4 KEYBOARD UNIT VOLUME PCB KEYBOARD PCB C L SIDE A L C www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 51 FH-2816ZF,2716ZF 1 2 3 4 1 2 3 4 D C B A VOLUME PCB KEYBOARD PCB C L SIDE B L C A CN953 A CN952 F CN1051 L CN956 C CN955 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 52 1 2 3 4 1 2 3 4 D C B A FH-2816ZF,2716ZF 4.5 EQ PCB D SIDE A A D EQ PCB CN301 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 53 FH-2816ZF,2716ZF 1 2 3 4 1 2 3 4 D C B A D SIDE B D EQ PCB www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 54 1 2 3 4 1 2 3 4 D C B A FH-2816ZF,2716ZF 4.7 CONNECTOR PCB E SIDE A SIDE B E CONNECTOR PCB E CONNECTOR PCB A CN801 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 55 FH-2816ZF,2716ZF 1 2 3 4 1 2 3 4 D C B A 4.8 VF SUB PCB F SIDE A SIDE B F VF SUB PCB F VF SUB PCB C CN954 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 56 1 2 3 4 1 2 3 4 D C B A FH-2816ZF,2716ZF A J I 4.8 CASSETTE MECHANISM MODULE DECK UNIT CN702 I www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 57 FH-2816ZF,2716ZF 1 2 3 4 1 2 3 4 C B A J PCB UNIT J PCB UNIT K REEL PCB K J K SIDE A SIDE B J I CN253 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com FH-2816ZF,2716ZF Unit Number : CWE1428 Unit Name : Tuner Unit MISCELLANEOUS IC 1 IC PA4023B IC 2 IC PA4024A Q 1 Transistor 2SC2712 Q 3 FET 3SK263 Q 31 Transistor 2SC2712 Q 151 Transistor DTC124EU Q 201 Transistor FC12 Q 203 Transistor DTC124EU Q 232 Transistor 2SC4116 D 3 Diode 1SV251 D 4 Diode 1SV250 D 5 Diode KV1410-F1 D 6 Diode MA157 D 7 Diode KV1410-F1 D 8 Diode KV1410-F1 D 201 Diode MA157 D 202 Diode 1SV251 D 231 Diode SVC203CP L 1 Inductor LCTBR12K2125 L 2 Coil CTC1145 L 3 Inductor LCTB4R7K2125 L 4 Coil CTC1131 L 5 Coil CTC1147 L 51 Ferri-Inductor LAU150K L 52 Coil CTC1136 L 201 Ferri-Inductor LAU4R7K L 202 Ferri-Inductor LAU330K L 203 Inductor CTF1371 L 208 Inductor LAU390K L 209 Ferri-Inductor LAU680K L 210 Coil CTB1103 T 31 Coil CTE1116 T 231 Coil CTB1106 TC 1 CCL1046 CF 25 Ceramic Filter CTF1292 CF 51 Ceramic Filter CTF1292 CF 52 Ceramic Filter CTF1292 CF 53 Ceramic Filter CTF1292 CF 230 CTF1262 CF 232 Ceramic Filter CTF1348 X 151 918.5Hz CSS1365 X 231 Crystal Resonator 10.26MHz CSS1111 VR 101 Semi-fixed 15k½(B) CCP1230 VR 151 Semi-fixed 10k½(B) CCP1229 VR 154 Semi-fixed 150k½(B) CCP1236 VR 156 Semi-fixed 68k½(B) CCP1235 RESISTORS R 3 RS1/16S223J R 4 RS1/16S101J R 5 RS1/16S101J R 6 RS1/16S101J R 7 RS1/10S331J R 8 RS1/16S473J R 9 RS1/16S473J R 10 RS1/16S223J R 11 RS1/16S124J R 12 RS1/16S474J R 15 RS1/16S271J R 16 RS1/16S104J R 17 RS1/16S473J R 18 RS1/16S473J R 19 RS1/16S154J R 27 RS1/16S0R0J R 31 RS1/16S470J R 32 RS1/16S912J R 33 RS1/16S912J R 34 RS1/16S331J R 35 RS1/16S331J R 39 RS1/16S0R0J R 51 RS1/16S331J R 55 RS1/16S102J R 56 RS1/16S823J R 61 RS1/16S392J R 62 RS1/16S273J R 103 RS1/16S333J R 104 RS1/16S334J R 105 RS1/16S683J R 107 RS1/16S222J R 152 RS1/16S393J R 155 RS1/16S303J R 157 RS1/10S203J R 160 RS1/16S222J R 161 RS1/16S563J R 162 RS1/16S225J R 163 RS1/16S222J R 164 RS1/16S473J R 165 RS1/16S102J R 202 RS1/16S223J R 203 RS1/16S225J R 204 RS1/16S103J R 205 RS1/16S471J R 206 RS1/16S220J R 207 RS1/16S101J R 208 RS1/16S102J R 209 RS1/16S0R0J R 214 RS1/16S563J R 215 RS1/16S473J =====Circuit Symbol and No.===Part Name Part No. --- ------ ------------------------------------------ ------------------------- =====Circuit Symbol and No.===Part Name Part No. --- ------ ------------------------------------------ ------------------------- B 5. ELECTRICAL PARTS LIST NOTE: - Parts whose parts numbers are omitted are subject to being not supplied. - The part numbers shown below indicate chip components. Chip Resistor RS1/_S___J,RS1/__S___J Chip Capacitor (except for CQS.....) CKS....., CCS....., CSZS..... 58 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 59 FH-2816ZF,2716ZF R 217 RS1/16S682J R 220 RS1/10S0R0J R 231 RS1/16S242J R 232 RS1/16S473J R 233 RS1/16S0R0J R 234 RS1/16S0R0J R 237 RS1/16S912J R 238 RS1/16S104J R 239 RS1/16S104J R 240 RS1/16S392J R 241 RS1/16S202J R 242 RS1/16S103J R 243 RS1/16S153J R 244 RS1/16S103J R 247 RS1/10S153J CAPACITORS C 1 CCSRCH220J50 C 2 CKSRYB222K50 C 3 CCSRCH6R0D50 C 5 CKSRYB222K50 C 6 CKSQYB473K16 C 7 CKSQYB473K16 C 8 CKSQYB104K16 C 9 CCSRCJ3R0C50 C 10 CEJA1R0M50 C 11 CCSRCH470J50 C 12 CCSRCH820J50 C 13 CKSRYB222K50 C 14 CCSRCH4R0C50 C 16 CCSRCH120J50 C 17 CKSRYB222K50 C 18 CKSRYB103K25 C 19 CKSRYB222K50 C 20 CKSRYB222K50 C 21 CEJA100M16 C 22 CCSRRH100D50 C 23 CCSRRH120J50 C 24 CKSRYB103K25 C 30 CCSRRH201J50 C 31 CKSRYB103K25 C 32 CKSQYB473K16 C 33 CCSRCK2R0C50 C 35 CCSRCH270J50 C 36 CCSRCH120J50 C 40 CKSRYB222K50 C 41 CKSQYB104K16 C 51 CKSRYB223K25 C 52 CKSRYB103K25 C 54 CCSRCH470J50 C 55 CKSQYB223K25 C 56 CKSQYB104K16 C 57 CKSRYB472K50 C 58 CEJA330M10 C 59 CKSRYB103K25 C 61 CCSRCH270J50 C 62 CKSRYB103K25 C 63 CEJAR22M50 C 65 CKSQYB104K16 C 101 CEJANP100M10 C 102 CKSRYB182K50 C 103 CKSQYB682K50 C 104 CEJA2R2M50 C 105 CKSRYB103K25 C 106 CCSRCH151J50 C 107 CKSRYB103K25 C 151 CKSRYB392K50 C 152 CKSQYB104K16 C 153 CEJA3R3M50 C 154 CKSQYB104K16 C 157 CEJA3R3M50 C 158 CKSYB474K16 C 159 CEJA220M6R3 C 160 CKSQYB104K16 C 161 CKSQYB104K16 C 162 CEJA3R3M50 C 163 CKSRYB102K50 C 165 CCSRCH100D50 C 201 CKSRYB103K25 C 202 CCSRCH100D50 C 203 CKSRYB332K50 C 204 CKSQYB473K16 C 205 CKSQYB473K16 C 206 CKSQYB103K25 C 207 CCSRCH120J50 C 211 CCSRCH560J50 C 212 CEJA101M10 C 213 CKSRYB103K25 C 215 CCSRCH680J50 C 216 CCSRCH101J50 C 217 CEJAR47M50 C 219 CKSRYB223K25 C 220 CKSRYB103K25 C 221 CKSRYB103K25 C 230 CKSQYB104K16 C 231 CCSRCH330J50 C 232 CCSRCH150J50 C 233 CKSRYB103K25 C 234 CEJA330M10 C 235 CKSRYB332K50 C 236 CKSQYB473K16 C 237 CCSRUJ221J50 C 239 CKSRYB103K25 C 240 CKSYB105K16 C 241 CKSQYB104K16 C 242 CEJAR47M50 C 243 CEJAR33M50 C 244 CKSQYB473K16 C 245 CKSQYB153K25 C 246 CKSQYB333K25 C 250 CCSRCJ3R0C50 Unit Number : CWX2016 Unit Name : Control Unit MISCELLANEOUS IC 101 IC UPC2572GS IC 201 IC UPD63702GF IC 202 IC TC4S66F IC 203 IC NJM062M IC 301 IC BA6997FP IC 302 IC BA6285FP IC 501 IC PD4501B IC 601 IC TA2063F IC 701 IC PQ05TZ51 Q 101 Transistor 2SD1664 Q 102 Transistor UMD2N Q 201 Transistor DTA114TU Q 202 Transistor UMD2N Q 601 Transistor 2SD1781K Q 602 Transistor 2SD1781K Q 603 Transistor 2SB709A D 601 Diode MA151WA D 701 Diode 1SR154-400 D 702 Diode 1SR154-400 D 801 Diode CL200IRX =====Circuit Symbol and No.===Part Name Part No. --- ------ ------------------------------------------ ------------------------- =====Circuit Symbol and No.===Part Name Part No. --- ------ ------------------------------------------ ------------------------- G www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 60 FH-2816ZF,2716ZF D 802 Diode CL200IRX L 501 Inductor CTF1305 X 201 Ceramic Resonator 16.93MHz CSS1363 S 801 Switch(Home) CSN1028 S 802 Switch(Clamp) CSN1028 EF 501 EMI Filter CCG1076 EF 701 EMI Filter CCG1051 RESISTORS R 101 RS1/8S100J R 102 RS1/8S120J R 103 RS1/16S102J R 104 RS1/16S822J R 105 RS1/16S682J R 106 RS1/16S183J R 107 RS1/16S822J R 108 RS1/16S333J R 109 RS1/16S683J R 110 RS1/16S134J R 111 RS1/16S273J R 112 RS1/16S222J R 113 RS1/16S103J R 114 RS1/16S103J R 115 RS1/16S102J R 116 RS1/16S163J R 117 RS1/16S163J R 118 RS1/16S223J R 119 RS1/16S223J R 201 RS1/16S104J R 202 RS1/16S473J R 203 RS1/16S102J R 204 RS1/16S473J R 205 RS1/16S103J R 207 RS1/16S103J R 505 RS1/16S102J R 507 RA4C102J R 508 RA4C681J R 601 RS1/16S102J R 602 RS1/16S102J R 603 RS1/16S223J R 604 RS1/16S223J R 605 RS1/16S162J R 606 RS1/16S162J R 607 RS1/16S103J R 801 RS1/8S751J R 802 RS1/8S751J CAPACITORS C 101 CEV101M6R3 C 102 CKSQYB104K16 C 103 CEV470M6R3 C 104 CKSYB334K16 C 105 CCSRCH330J50 C 106 CKSRYB103K25 C 107 CEV4R7M35 C 108 CKSQYB273K50 C 109 CCSRCH101J50 C 110 CKSQYB104K16 C 111 CKSRYB332K50 C 112 CKSQYB473K16 C 113 CKSRYB103K25 C 114 CKSRYB391K50 C 115 CCSRCH121J50 C 116 CKSRYB682K25 C 117 CKSRYB333K16 C 118 CKSYB334K16 C 119 CKSYB334K16 C 120 CKSYB334K16 C 121 CKSYB334K16 C 122 CKSQYB104K16 C 123 CKSRYB472K50 C 124 CKSQYB104K16 C 125 CCSRCH6R0D50 C 126 CKSRYB153K25 C 127 CCSRCH102J25 C 128 CKSRYB473K16 C 129 CKSRYB152K50 C 201 CKSYB334K16 C 202 CKSQYB104K16 C 203 CKSQYB104K16 C 204 CKSQYB104K16 C 205 CKSRYB332K50 C 206 CKSQYB104K16 C 303 CEV470M16 C 304 CKSRYB103K25 C 305 CKSRYB103K25 C 306 CKSRYB103K25 C 307 CEV100M25 C 502 CKSRYB471K50 C 503 CCSRCH100D50 C 601 CEV101M6R3 C 602 CKSQYB104K16 C 603 CEV4R7M35 C 604 CEV4R7M35 C 605 CKSRYB152K50 C 606 CKSRYB152K50 C 607 CEV220M6R3 C 701 22µF/6.3V CCH1233 C 702 CKSYB334K16 C 703 CEV101M6R3 C 901 CCSRCH471J50 C 902 CCSRCH271J50 C 903 CCSRCH471J50 C 904 CCSRCH101J50 Unit Number : HWM5106(FH-2816ZF/X1H/UC) Unit Name : Mother Unit MISCELLANEOUS IC 101 IC SN761027DL IC 102 IC SN761027DL IC 212 IC BA4558F-P IC 213 IC BA14741F IC 215 IC BA3308F IC 301 IC TDA7384 IC 302 IC NJM2068MD IC 303 IC NJM2068MD IC 304 IC NJM2068MD IC 401 IC LA1061M IC 501 IC LC72146M IC 502 IC MC13020M IC 503 IC PD6181B IC 504 IC PMW001B IC 505 IC SC14SU69F IC 601 IC PD4692D IC 602 IC PD4693D IC 604 IC TC7S86F IC 605 IC TC35096AF IC 606 IC S-29220A IC 607 IC NJM2904M IC 801 IC PAJ002A IC 802 IC PA2024A Q 301 Transistor DTC124EK Q 302 Transistor DTC124EK =====Circuit Symbol and No.===Part Name Part No. --- ------ ------------------------------------------ ------------------------- =====Circuit Symbol and No.===Part Name Part No. --- ------ ------------------------------------------ ------------------------- A www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 61 FH-2816ZF,2716ZF Q 304 Transistor FMC2A Q 307 Transistor FMC4A Q 308 Transistor FMC4A Q 311 Transistor FMC4A Q 312 Transistor FMC4A Q 313 Transistor 2SC2458 Q 315 Transistor DTC323TK Q 316 Transistor DTC323TK Q 317 Transistor DTC323TK Q 318 Transistor DTC323TK Q 319 Transistor DTA114TK Q 320 Transistor DTA114TK Q 323 Transistor DTC124TK Q 401 Transistor 2SC4116 Q 402 Transistor 2SC4116 Q 403 Transistor DTA124EK Q 404 Transistor DTC124EK Q 405 Transistor DTC124EK Q 501 Transistor DTC114TK Q 502 Transistor 2SC4116 Q 503 Transistor 2SK330 Q 505 Transistor 2SC2458 Q 506 Transistor 2SK330 Q 552 Transistor 2SC2458 Q 553 Transistor 2SC2458 Q 603 Transistor 2SB1238 Q 616 Transistor 2SA1048 Q 617 Transistor DTC124EK Q 618 Transistor 2SD2396 Q 619 Transistor DTA114EK Q 620 Transistor DTC114EK Q 621 Transistor DTA124EK Q 622 Transistor DTC343TK Q 623 Transistor DTC343TK Q 625 Transistor DTC124EK Q 626 Transistor DTC114TK Q 627 Transistor DTC114TK Q 628 Transistor DTC124TK Q 629 Transistor DTC114TK Q 630 Transistor DTA114TK Q 631 Transistor DTC124EK Q 801 Transistor 2SA1048 Q 802 Transistor DTC124EK Q 803 Transistor 2SA1358 Q 805 Transistor 2SA1358 Q 806 Transistor 2SC2458 Q 807 Transistor 2SC2458 D 201 Diode MA8039(L) D 301 Diode MA3047(M) D 302 Diode HZS6L(B2) D 303 Diode 1SS133 D 401 Diode 1SV128A D 402 Diode 1SV128A D 403 Diode 1SS133 D 404 Diode 1SS133 D 406 Diode 1SS133 D 501 Diode 1SS133 D 502 Diode 1SS133 D 503 Diode RD3R0ES D 504 Diode MA3047(M) D 505 Diode 1SS133 D 506 Diode 1SS133 D 507 Diode 1SS133 D 508 Diode 1SS133 D 511 Diode RD3R0ES D 605 Diode HZS9L(B1) D 607 Chip Diode MA151WK D 613 Diode 1SS133 D 614 Diode 1SS133 D 616 Diode 1SS352 D 617 Diode 1SS133 D 618 Diode 1SS133 D 619 Diode 1SS133 D 620 Diode 1SS133 D 621 Diode 1SS133 D 622 Diode 1SS133 D 801 Diode ERC05-10B D 802 Diode ERA15-02VH D 803 Diode 1SS133 D 804 Diode 1SS133 D 1601 Diode 1SS352 L 401 Inductor LCTBR15K2125 L 402 Inductor LCTBR15K2125 L 403 Inductor LCTB4R7K2125 L 404 Inductor LCTBR15K2125 L 405 Ferri-Inductor LAU4R7K L 406 Ferri-Inductor LAU4R7K L 407 Inductor LCTA561J4532 L 501 Ferri-Inductor LAU1R0M L 502 Inductor LCTB2R2K2125 L 503 Ferri-Inductor CTF-157 L 504 Inductor LCTB2R2K2125 L 505 Inductor LCTB2R2K2125 L 508 Inductor LCTB2R2K2125 L 601 Inductor LCTB2R2K2125 L 602 Inductor LCTB2R2K2125 L 801 Choke Coil 600µH CTH1171 TH 601 Thermistor CCX1015 X 501 Crystal Resonator 7.2MHz CSS1334 X 502 Crystal Resonator 4.332MHz CSS1056 X 503 Ceramic Resonator 3.600MHz CSS1302 X 601 Crystal Resonator 4.1952MHz CSS1398 X 602 Ceramic Resonator 4.194MHz CSS1071 X 603 Resonator 32.768kHz CSS1319 EF 801 EMI Filter CCG1006 AR 401 DSP-201M AR 402 DSP-201M RESISTORS R 1 RS1/10S0R0J R 4 RS1/10S0R0J R 103 RS1/10S911J R 104 RS1/10S911J R 105 RS1/10S182J R 106 RS1/10S182J R 107 RS1/10S363J R 108 RS1/10S363J R 109 RS1/10S103J R 110 RS1/10S103J R 111 RS1/10S103J R 112 RS1/10S103J R 113 RS1/10S0R0J R 114 RS1/10S0R0J R 115 RS1/10S473J R 116 RS1/10S473J R 117 RS1/10S473J R 118 RS1/10S473J R 119 RS1/10S473J R 120 RS1/10S473J =====Circuit Symbol and No.===Part Name Part No. --- ------ ------------------------------------------ ------------------------- =====Circuit Symbol and No.===Part Name Part No. --- ------ ------------------------------------------ ------------------------- www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 62 FH-2816ZF,2716ZF R 127 RS1/10S221J R 128 RS1/10S221J R 139 RS1/10S151J R 140 RS1/10S151J R 145 RS1/10S182J R 146 RS1/10S182J R 147 RS1/10S103J R 148 RS1/10S103J R 301 RS1/10S103J R 302 RS1/10S221J R 303 RS1/10S101J R 304 RS1/10S153J R 305 RS1/10S103J R 308 RS1/10S182J R 309 RS1/10S182J R 310 RS1/10S333J R 311 RS1/10S333J R 312 RS1/10S753J R 313 RS1/10S753J R 314 RS1/10S753J R 315 RS1/10S753J R 316 RS1/10S333J R 317 RS1/10S333J R 318 RS1/10S333J R 319 RS1/10S333J R 320 RS1/10S753J R 321 RS1/10S753J R 322 RS1/10S152J R 323 RS1/10S222J R 324 RS1/10S151J R 329 RS1/10S331J R 330 RS1/10S102J R 331 RS1/10S473J R 333 RS1/10S333J R 334 RS1/10S392J R 337 RS1/10S102J R 345 RS1/10S223J R 346 RS1/10S223J R 347 RS1/10S223J R 348 RS1/10S223J R 361 RS1/10S103J R 362 RS1/10S473J R 363 RS1/10S103J R 364 RS1/10S432J R 366 RS1/10S103J R 401 RS1/10S391J R 402 RS1/10S471J R 403 RS1/10S103J R 404 RS1/10S103J R 405 RS1/10S104J R 406 RS1/10S103J R 407 RS1/10S473J R 408 RS1/10S182J R 409 RS1/10S683J R 410 RS1/10S334J R 411 RS1/10S104J R 412 RS1/10S104J R 413 RS1/10S473J R 414 RS1/10S224J R 415 RS1/10S101J R 416 RS1/10S101J R 418 RS1/10S104J R 419 RS1/10S104J R 420 RS1/10S103J R 421 RS1/10S472J R 501 RS1/10S153J R 502 RS1/10S223J R 503 RS1/10S103J R 504 RS1/10S472J R 505 RS1/10S472J R 506 RS1/10S102J R 507 RS1/10S222J R 508 RS1/10S102J R 509 RS1/10S152J R 510 RS1/10S103J R 511 RS1/10S222J R 512 RS1/10S102J R 513 RS1/10S472J R 514 RS1/10S472J R 515 RS1/10S152J R 516 RS1/10S222J R 517 RS1/10S222J R 519 RS1/10S473J R 520 RS1/10S473J R 521 RS1/10S473J R 522 RS1/10S473J R 523 RS1/10S473J R 524 RS1/10S473J R 525 RS1/10S473J R 530 RD1/4PU101J R 533 RS1/10S222J R 535 RS1/10S681J R 536 RS1/10S681J R 537 RS1/10S681J R 538 RS1/10S473J R 539 RS1/10S473J R 540 RS1/10S473J R 542 RS1/10S473J R 549 RS1/10S681J R 550 RS1/10S102J R 551 RS1/10S102J R 553 RS1/10S102J R 554 RS1/10S681J R 555 RS1/10S105J R 556 RS1/10S102J R 558 RS1/10S473J R 559 RS1/10S681J R 561 RS1/10S473J R 562 RS1/10S473J R 564 RS1/10S0R0J R 565 RS1/10S0R0J R 566 RS1/10S472J R 567 RS1/10S472J R 570 RS1/10S103J R 571 RS1/10S103J R 572 RS1/10S823J R 573 RS1/10S431J R 574 RS1/10S152J R 575 RS1/10S563J R 576 RS1/10S224J R 577 RS1/10S472J R 578 RS1/10S152J R 579 RS1/10S911J R 580 RS1/10S272J R 581 RS1/10S431J R 582 RS1/10S103J R 583 RS1/10S103J R 587 RS1/10S203J R 588 RS1/10S203J R 589 RS1/10S222J =====Circuit Symbol and No.===Part Name Part No. --- ------ ------------------------------------------ ------------------------- =====Circuit Symbol and No.===Part Name Part No. --- ------ ------------------------------------------ ------------------------- www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 63 FH-2816ZF,2716ZF R 591 RS1/10S102J R 592 RS1/10S102J R 593 RS1/10S225J R 594 RS1/10S473J R 596 RS1/10S333J R 597 RS1/10S333J R 598 RD1/4PU222J R 599 RD1/4PU222J R 601 RS1/10S473J R 602 RS1/10S473J R 603 RS1/10S102J R 604 RS1/10S102J R 605 RS1/10S102J R 622 RS1/16S102J R 624 RS1/16S471J R 629 RS1/10S102J R 630 RS1/10S473J R 631 RS1/10S102J R 634 RS1/10S103J R 635 RS1/10S473J R 636 RS1/10S102J R 637 RS1/10S102J R 650 RS1/10S102J R 659 RS1/10S102J R 660 RS1/10S102J R 661 RS1/10S102J R 662 RS1/10S102J R 665 RS1/10S102J R 666 RS1/10S101J R 667 RS1/10S101J R 668 RS1/16S101J R 669 RS1/10S101J R 670 RS1/10S471J R 673 RS1/10S473J R 674 RS1/10S471J R 675 RS1/10S472J R 676 RS1/10S472J R 677 RS1/10S471J R 695 RS1/16S102J R 697 RS1/10S472J R 698 RS1/10S681J R 699 RS1/10S102J R 701 RS1/16S102J R 702 RS1/16S681J R 711 RS1/10S102J R 712 RS1/10S102J R 713 RS1/10S102J R 714 RS1/10S102J R 715 RS1/10S102J R 716 RS1/10S102J R 717 RS1/10S102J R 718 RS1/10S513J R 719 RS1/10S473J R 720 RS1/10S473J R 721 RS1/10S473J R 722 RS1/10S473J R 723 RS1/10S473J R 724 RS1/10S473J R 725 RS1/16S223J R 726 RS1/16S223J R 728 RS1/16S222J R 729 RS1/16S222J R 730 RS1/10S103J R 731 RS1/10S184J R 732 RS1/10S152J R 733 RS1/10S472J R 734 RS1/10S473J R 735 RS1/10S473J R 737 RS1/10S473J R 754 RS1/10S473J R 755 RS1/10S473J R 756 RS1/10S273J R 757 RS1/10S104J R 758 RS1/10S104J R 759 RS1/10S472J R 760 RS1/10S273J R 761 RS1/10S473J R 776 RS1/10S103J R 777 RS1/8S201J R 778 RD1/4PU221J R 779 RS1/10S221J R 780 RS1/10S472J R 781 RS1/10S103J R 782 RS1/10S223J R 783 RS1/10S471J R 784 RS1/10S102J R 785 RS1/10S473J R 786 RS1/10S392J R 787 RS1/10S472J R 788 RS1/10S471J R 789 RS1/10S471J R 790 RS1/10S471J R 791 RS1/10S471J R 792 RS1/10S102J R 793 RS1/10S472J R 794 RS1/10S103J R 795 RS1/16S471J R 796 RS1/16S471J R 797 RS1/16S471J R 798 RS1/16S471J R 799 RS1/10S472J R 801 RS1/10S152J R 802 RS1/10S103J R 803 RS1/10S103J R 804 RS1/10S822J R 805 RS1/10S823J R 806 RS1/10S823J R 807 RS1/10S103J R 808 RS1/10S333J R 809 RS1/10S363J R 810 RS1/10S103J R 811 RS1/4S4R7J R 812 RS1/10S102J R 814 RS1/10S394J R 815 RS1/10S274J R 817 RS1/10S472J R 818 RS1/10S104J R 819 RS1/4S4R7J R 820 RS1/10S152J R 821 RS1/10S222J R 822 RS1/10S102J R 823 RS1/10S105J R 824 RS1/10S473J R 825 RS1/10S103J R 826 RS1/10S273J R 1221 RS1/10S103J R 1222 RS1/10S103J R 1223 RS1/10S103J R 1224 RS1/10S103J R 1226 RS1/16S103J =====Circuit Symbol and No.===Part Name Part No. --- ------ ------------------------------------------ ------------------------- =====Circuit Symbol and No.===Part Name Part No. --- ------ ------------------------------------------ ------------------------- www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 64 FH-2816ZF,2716ZF R 1227 RS1/16S242J R 1228 RS1/16S101J R 1229 RS1/16S910J R 1231 RS1/16S112J R 1233 RS1/16S753J R 1235 RS1/16S0R0J R 1237 RS1/16S122J R 1239 RS1/16S753J R 1241 RS1/16S472J R 1243 RS1/16S513J R 1245 RS1/16S473J R 1247 RS1/10S113J R 1249 RS1/10S562J R 1251 RS1/10S392J R 1253 RS1/10S221J R 1255 RS1/10S752J R 1257 RS1/16S684J R 1259 RS1/16S472J R 1615 RS1/10S101J R 1616 RS1/10S103J R 1617 RS1/10S822J R 1618 RS1/10S103J R 1619 RS1/10S473J R 1620 RS1/10S182J R 1621 RS1/10S182J R 1622 RS1/10S102J R 1623 RS1/10S102J R 1631 RA4C102J R 1632 RA4C102J R 1633 RA4C102J R 1634 RA4C102J R 1635 RA4C102J R 1636 RA4C102J R 1637 RA4C682J R 1638 RA4C102J R 1640 RA4C102J R 1641 RA4C102J R 1642 RA4C222J R 1643 RA4C473J R 1644 RA4C473J R 1645 RA4C221J R 1648 RA4C102J R 1649 RS1/10S220J R 1650 RS1/16S102J R 1651 RS1/16S102J R 1652 RS1/16S102J R 1653 RS1/16S102J R 1654 RS1/10S362J R 1655 RS1/10S362J R 1656 RS1/10S473J CAPACITORS C 103 CEJANP100M16 C 104 CEJANP100M16 C 105 CEAL1R0M50 C 106 CEAL1R0M50 C 107 CEJANP100M16 C 108 CEJANP100M16 C 111 CKSQYB103K50 C 112 CKSQYB103K50 C 113 CKSQYB561K50 C 114 CKSQYB561K50 C 115 CEJANP3R3M25 C 116 CEJANP3R3M25 C 119 CKSQYB563K16 C 120 CKSQYB563K16 C 121 CEJANPR33M50 C 122 CEJANPR33M50 C 123 CEAL220M6R3 C 124 CEAL2R2M50 C 125 CKSQYB683K16 C 126 CKSQYB154K16 C 127 CEAL101M10 C 128 CEJANP100M16 C 129 CEJANP100M16 C 130 CEJANP100M16 C 131 CEJANP100M16 C 138 CEAL2R2M50 C 139 CEAL220M6R3 C 140 CKSQYB683K16 C 143 CEALNP1R0M50 C 144 CEALNP1R0M50 C 145 CEALNP1R0M50 C 146 CEALNP1R0M50 C 147 CEALNP1R0M50 C 148 CEALNP1R0M50 C 149 CEALNP1R0M50 C 150 CEALNP1R0M50 C 151 CEALNP1R0M50 C 152 CEALNP1R0M50 C 153 CEALNP1R0M50 C 154 CEALNP1R0M50 C 155 CEALNP1R0M50 C 156 CEALNP1R0M50 C 157 CEALNP1R0M50 C 158 CEALNP1R0M50 C 159 CEAL100M16 C 160 CEAL100M16 C 161 CEAL100M16 C 162 CEAL100M16 C 163 CEAL150M10 C 164 CEAL150M10 C 165 CEAL1R0M50 C 166 CEAL1R0M50 C 189 CKSQYB273K50 C 291 CKSQYB102K50 C 293 CKSYB684K16 C 295 CKSYB274K16 C 297 CKSQYB124K16 C 299 CKSQYB394K16 C 305 CKSQYB104K50 C 306 CEAL330M10 C 307 CEAL1R0M50 C 308 CEAL1R0M50 C 309 CEAL100M16 C 314 CEAL100M16 C 315 CEAL100M16 C 316 CEAL100M16 C 317 CEAL100M16 C 318 CCSQCH470J50 C 319 CCSQCH470J50 C 320 CEAL100M16 C 321 CEAL100M16 C 322 CCSQCH101J50 C 323 CEAL100M16 C 324 CEJA101M16 C 325 CEAL100M16 C 326 CEAS331M6R3 C 329 CCSQCH471J50 C 331 CCSQCH470J50 C 332 CCSQCH470J50 C 333 CCSQCH101J50 =====Circuit Symbol and No.===Part Name Part No. --- ------ ------------------------------------------ ------------------------- =====Circuit Symbol and No.===Part Name Part No. --- ------ ------------------------------------------ ------------------------- www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 65 FH-2816ZF,2716ZF C 335 CKSYB105K16 C 336 CKSYB105K16 C 337 CKSYB105K16 C 338 CKSYB105K16 C 343 CEAL220M16 C 344 CEAL220M16 C 345 CEAL100M16 C 346 CEAL4R7M16 C 347 CEAL4R7M16 C 348 CCSQCH221J50 C 349 CKSQYB103K50 C 401 CCSQCH220J50 C 402 CCSQCH220J50 C 403 CCSQCH150J50 C 404 CCSQCH150J50 C 405 CCSQCH390J50 C 406 CKSQYB222K50 C 407 CKSQYB472K50 C 408 CEAL100M16 C 409 CKSQYB103K50 C 410 CKSQYB103K50 C 412 CKSQYB103K50 C 413 CKSQYB103K50 C 414 CKSQYB392K50 C 417 CEAL2R2M50 C 418 CKSQYB102K50 C 419 CKSQYB103K50 C 421 CKSQYB102K50 C 501 CEAL100M16 C 502 CKSQYB103K50 C 504 CKSQYB223K50 C 505 CCSQCH101J50 C 506 CEAL100M16 C 507 CCSQCH101J50 C 508 CCSQCH101J50 C 509 CCSQCH101J50 C 510 CKSQYB103K50 C 511 CFTNA474J50 C 512 0.047µF/16V CCG1008 C 513 CKSQYB103K50 C 514 4.7µF/16V CCH1005 C 515 CKSQYB273K50 C 516 CKSQYB273K50 C 517 CKSQYB103K50 C 519 CKSQYB223K50 C 520 CKSQYB102K50 C 521 CCSQCH101J50 C 522 CCSQCH150J50 C 523 CCSQCH150J50 C 527 CKSQYB104K50 C 528 CCSQCH101J50 C 530 CKSYB105K16 C 531 CKSQYB104K50 C 532 CKSQYB472K50 C 533 CEAL100M16 C 534 CKSQYB223K50 C 535 CKSQYB104K50 C 536 CCSQCH101J50 C 537 CKSQYB104K50 C 538 CEAL4R7M16 C 539 CKSQYB473K50 C 540 CKSQYB102K50 C 542 CCSQCH270J50 C 543 CCSQCH270J50 C 544 CEAL1R0M50 C 545 CEAL1R0M50 C 546 CKSQYB562K50 C 547 CKSQYB562K50 C 548 CEAL330M10 C 549 CEAL2R2M50 C 550 CKSYB124K25 C 551 CKSYB124K25 C 552 CKSQYB332K50 C 553 CEAL100M16 C 554 CKSQYB103K50 C 555 CKSQYB332K50 C 556 CKSQYB332K50 C 558 CFTLA474J50 C 559 CSZA4R7K10 C 560 CSZA100M10 C 561 CFTLA474J50 C 562 CSZA2R2K16 C 563 CCSQCH510J50 C 564 CKSQYB103K50 C 565 CEAL470M10 C 566 CKSQYB332K50 C 567 CKSYB102K50 C 568 CCSQCH101J50 C 571 CEAL4R7M16 C 601 CCSQCH101J50 C 602 CCSQCH101J50 C 603 CCSQCH220J50 C 604 CCSQCH180J50 C 605 CCSQCH220J50 C 606 CCSQCH220J50 C 608 CCSQCH101J50 C 609 CCSQCH681J50 C 610 CCSQCH681J50 C 619 CEAL100M16 C 620 CEAL100M16 C 621 CEAL100M16 C 622 CCSQCH181J50 C 623 CCSQCH181J50 C 624 CASA100M6R3 C 635 CKSQYB104K16 C 636 CKSQYB473K50 C 637 CKSQYB103K50 C 645 CKSQYB102K50 C 646 CKSQYB473K50 C 651 CKSQYB103K50 C 652 CEAL1R0M50 C 653 CEAL1R0M50 C 654 CEAL101M10 C 656 CEAL100M16 C 657 CKSQYB103K50 C 659 CKSQYB103K50 C 660 CEAL2R2M50 C 661 CKSQYB472K50 C 662 CKSQYB472K50 C 663 CKSQYB104K16 C 801 4700µF/16V CCH1188 C 802 CKSQYB103K50 C 803 CKSQYB103K50 C 804 CEAS102M16 C 805 CKSQYB473K50 C 806 CEAS471M6R3 C 807 CASA100M6R3 C 808 CEAS331M10 C 809 CEAS221M10 C 810 CASA101M10 =====Circuit Symbol and No.===Part Name Part No. --- ------ ------------------------------------------ ------------------------- =====Circuit Symbol and No.===Part Name Part No. --- ------ ------------------------------------------ ------------------------- www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 66 FH-2816ZF,2716ZF C 811 CASA470M10 C 812 CEAL101M10 C 813 CKSQYB472K50 C 814 CKSQYB103K50 C 815 CKSQYB102K50 C 816 CKSQYB102K50 C 819 CSZA220M10 C 821 CKSQYB102K50 C 822 CKSQYB102K50 C 823 CKSQYB102K50 C 824 CKSQYB102K50 C 825 CKSQYB102K50 C 826 CKSQYB102K50 C 827 CKSQYB102K50 C 828 CKSQYB102K50 C 829 0.1F/5.5V CCL1027 C 1201 CKSQYB332K50 C 1203 CKLSR563K16 C 1205 CKLSB333K50 C 1207 CEALR15M50 C 1209 CEJA221M6R3 C 1213 CEAL6R8M35 C 1214 CKSQYB102K50 C 1220 CKSQYB104K16 C 1580 CKSQYB332K50 Unit Number : HWM5104(FH-2716ZF/X1H/UC) Unit Name : Mother Unit MISCELLANEOUS IC 101 IC SN761027DL IC 102 IC SN761027DL IC 212 IC BA4558F-P IC 213 IC BA14741F IC 215 IC BA3308F IC 301 IC TDA7384 IC 302 IC NJM2068MD IC 303 IC NJM2068MD IC 304 IC NJM2068MD IC 501 IC LC72146M IC 502 IC MC13020M IC 503 IC PD6181B IC 504 IC PMW001B IC 505 IC SC14SU69F IC 601 IC PD4692D IC 602 IC PD4693D IC 604 IC TC7S86F IC 605 IC TC35096AF IC 606 IC S-29220A IC 607 IC NJM2904M IC 801 IC PAJ002A IC 802 IC PA2024A Q 301 Transistor DTC124EK Q 302 Transistor DTC124EK Q 304 Transistor FMC2A Q 307 Transistor FMC4A Q 308 Transistor FMC4A Q 311 Transistor FMC4A Q 312 Transistor FMC4A Q 313 Transistor 2SC2458 Q 315 Transistor DTC323TK Q 316 Transistor DTC323TK Q 317 Transistor DTC323TK Q 318 Transistor DTC323TK Q 319 Transistor DTA114TK Q 320 Transistor DTA114TK Q 323 Transistor DTC124TK Q 501 Transistor DTC114TK Q 502 Transistor 2SC4116 Q 503 Transistor 2SK330 Q 505 Transistor 2SC2458 Q 506 Transistor 2SK330 Q 552 Transistor 2SC2458 Q 553 Transistor 2SC2458 Q 603 Transistor 2SB1238 Q 616 Transistor 2SA1048 Q 617 Transistor DTC124EK Q 618 Transistor 2SD2396 Q 619 Transistor DTA114EK Q 620 Transistor DTC114EK Q 621 Transistor DTA124EK Q 622 Transistor DTC343TK Q 623 Transistor DTC343TK Q 625 Transistor DTC124EK Q 626 Transistor DTC114TK Q 627 Transistor DTC114TK Q 628 Transistor DTC124TK Q 629 Transistor DTC114TK Q 630 Transistor DTA114TK Q 631 Transistor DTC124EK Q 801 Transistor 2SA1048 Q 802 Transistor DTC124EK Q 803 Transistor 2SA1358 Q 805 Transistor 2SA1358 Q 806 Transistor 2SC2458 Q 807 Transistor 2SC2458 D 201 Diode MA8039(L) D 301 Diode MA3047(M) D 302 Diode HZS6L(B2) D 303 Diode 1SS133 D 501 Diode 1SS133 D 502 Diode 1SS133 D 503 Diode RD3R0ES D 504 Diode MA3047(M) D 505 Diode 1SS133 D 506 Diode 1SS133 D 507 Diode 1SS133 D 508 Diode 1SS133 D 511 Diode RD3R0ES D 605 Diode HZS9L(B1) D 607 Chip Diode MA151WK D 613 Diode 1SS133 D 614 Diode 1SS133 D 616 Diode 1SS352 D 617 Diode 1SS133 D 618 Diode 1SS133 D 619 Diode 1SS133 D 620 Diode 1SS133 D 621 Diode 1SS133 D 622 Diode 1SS133 D 801 Diode ERC05-10B D 802 Diode ERA15-02VH D 803 Diode 1SS133 D 804 Diode 1SS133 D 1601 Diode 1SS352 L 403 Inductor LCTB4R7K2125 L 501 Ferri-Inductor LAU1R0M L 502 Inductor LCTB2R2K2125 L 503 Ferri-Inductor CTF-157 L 504 Inductor LCTB2R2K2125 L 505 Inductor LCTB2R2K2125 L 508 Inductor LCTB2R2K2125 L 601 Inductor LCTB2R2K2125 L 602 Inductor LCTB2R2K2125 L 801 Choke Coil 600µH CTH1171 TH 601 Thermistor CCX1015 X 501 Crystal Resonator 7.2MHz CSS1334 X 502 Crystal Resonator 4.332MHz CSS1056 X 503 Ceramic Resonator 3.600MHz CSS1302 X 601 Crystal Resonator 4.1952MHz CSS1398 =====Circuit Symbol and No.===Part Name Part No. --- ------ ------------------------------------------ ------------------------- =====Circuit Symbol and No.===Part Name Part No. --- ------ ------------------------------------------ ------------------------- A www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 67 FH-2816ZF,2716ZF X 602 Ceramic Resonator 4.194MHz CSS1071 X 603 Resonator 32.768kHz CSS1319 EF 801 EMI Filter CCG1006 AR 402 DSP-201M RESISTORS R 4 RS1/10S0R0J R 103 RS1/10S911J R 104 RS1/10S911J R 105 RS1/10S182J R 106 RS1/10S182J R 107 RS1/10S363J R 108 RS1/10S363J R 109 RS1/10S103J R 110 RS1/10S103J R 111 RS1/10S103J R 112 RS1/10S103J R 113 RS1/10S0R0J R 114 RS1/10S0R0J R 115 RS1/10S473J R 116 RS1/10S473J R 117 RS1/10S473J R 118 RS1/10S473J R 119 RS1/10S473J R 120 RS1/10S473J R 127 RS1/10S221J R 128 RS1/10S221J R 139 RS1/10S151J R 140 RS1/10S151J R 145 RS1/10S182J R 146 RS1/10S182J R 147 RS1/10S103J R 148 RS1/10S103J R 301 RS1/10S103J R 302 RS1/10S221J R 303 RS1/10S101J R 304 RS1/10S153J R 305 RS1/10S103J R 308 RS1/10S182J R 309 RS1/10S182J R 310 RS1/10S333J R 311 RS1/10S333J R 312 RS1/10S753J R 313 RS1/10S753J R 314 RS1/10S753J R 315 RS1/10S753J R 316 RS1/10S333J R 317 RS1/10S333J R 318 RS1/10S333J R 319 RS1/10S333J R 320 RS1/10S753J R 321 RS1/10S753J R 322 RS1/10S152J R 323 RS1/10S222J R 324 RS1/10S151J R 329 RS1/10S331J R 330 RS1/10S102J R 331 RS1/10S473J R 333 RS1/10S333J R 334 RS1/10S392J R 337 RS1/10S102J R 345 RS1/10S223J R 346 RS1/10S223J R 347 RS1/10S223J R 348 RS1/10S223J R 361 RS1/10S103J R 362 RS1/10S473J R 363 RS1/10S103J R 364 RS1/10S432J R 366 RS1/10S103J R 417 RS1/10S0R0J R 501 RS1/10S153J R 502 RS1/10S223J R 503 RS1/10S103J R 504 RS1/10S472J R 505 RS1/10S472J R 506 RS1/10S102J R 507 RS1/10S222J R 508 RS1/10S102J R 509 RS1/10S152J R 510 RS1/10S103J R 511 RS1/10S222J R 512 RS1/10S102J R 513 RS1/10S472J R 514 RS1/10S472J R 515 RS1/10S152J R 516 RS1/10S222J R 517 RS1/10S222J R 519 RS1/10S473J R 520 RS1/10S473J R 521 RS1/10S473J R 522 RS1/10S473J R 523 RS1/10S473J R 524 RS1/10S473J R 525 RS1/10S473J R 530 RD1/4PU101J R 533 RS1/10S222J R 535 RS1/10S681J R 536 RS1/10S681J R 537 RS1/10S681J R 538 RS1/10S473J R 539 RS1/10S473J R 540 RS1/10S473J R 542 RS1/10S473J R 549 RS1/10S681J R 550 RS1/10S102J R 551 RS1/10S102J R 553 RS1/10S102J R 554 RS1/10S681J R 555 RS1/10S105J R 556 RS1/10S102J R 558 RS1/10S473J R 559 RS1/10S681J R 561 RS1/10S473J R 562 RS1/10S473J R 564 RS1/10S0R0J R 565 RS1/10S0R0J R 566 RS1/10S472J R 567 RS1/10S472J R 570 RS1/10S103J R 571 RS1/10S103J R 572 RS1/10S823J R 573 RS1/10S431J R 574 RS1/10S152J R 575 RS1/10S563J R 576 RS1/10S224J R 577 RS1/10S472J R 578 RS1/10S152J R 579 RS1/10S911J R 580 RS1/10S272J R 581 RS1/10S431J =====Circuit Symbol and No.===Part Name Part No. --- ------ ------------------------------------------ ------------------------- =====Circuit Symbol and No.===Part Name Part No. --- ------ ------------------------------------------ ------------------------- www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 68 FH-2816ZF,2716ZF R 582 RS1/10S103J R 583 RS1/10S103J R 587 RS1/10S203J R 588 RS1/10S203J R 589 RS1/10S222J R 591 RS1/10S102J R 592 RS1/10S102J R 593 RS1/10S225J R 594 RS1/10S473J R 596 RS1/10S333J R 597 RS1/10S333J R 598 RD1/4PU222J R 599 RD1/4PU222J R 601 RS1/10S473J R 602 RS1/10S473J R 603 RS1/10S102J R 604 RS1/10S102J R 605 RS1/10S102J R 622 RS1/16S102J R 624 RS1/16S471J R 629 RS1/10S102J R 630 RS1/10S473J R 631 RS1/10S102J R 634 RS1/10S103J R 635 RS1/10S473J R 636 RS1/10S102J R 637 RS1/10S102J R 650 RS1/10S102J R 659 RS1/10S102J R 660 RS1/10S102J R 661 RS1/10S102J R 662 RS1/10S102J R 665 RS1/10S102J R 666 RS1/10S101J R 667 RS1/10S101J R 668 RS1/16S101J R 669 RS1/10S101J R 670 RS1/10S471J R 673 RS1/10S473J R 674 RS1/10S471J R 675 RS1/10S472J R 676 RS1/10S472J R 677 RS1/10S471J R 695 RS1/16S102J R 697 RS1/10S472J R 698 RS1/10S681J R 699 RS1/10S102J R 701 RS1/16S102J R 702 RS1/16S681J R 711 RS1/10S102J R 712 RS1/10S102J R 713 RS1/10S102J R 714 RS1/10S102J R 715 RS1/10S102J R 716 RS1/10S102J R 717 RS1/10S102J R 718 RS1/10S513J R 719 RS1/10S473J R 720 RS1/10S473J R 721 RS1/10S473J R 722 RS1/10S473J R 723 RS1/10S473J R 724 RS1/10S473J R 725 RS1/16S223J R 726 RS1/16S223J R 728 RS1/16S222J R 729 RS1/16S222J R 730 RS1/10S103J R 731 RS1/10S184J R 732 RS1/10S152J R 733 RS1/10S472J R 734 RS1/10S473J R 735 RS1/10S473J R 737 RS1/10S473J R 740 RS1/10S334J R 741 RS1/10S244J R 742 RS1/10S104J R 743 RS1/10S104J R 754 RS1/10S473J R 755 RS1/10S473J R 756 RS1/10S273J R 757 RS1/10S104J R 758 RS1/10S104J R 759 RS1/10S472J R 760 RS1/10S273J R 761 RS1/10S473J R 776 RS1/10S103J R 777 RS1/8S201J R 778 RD1/4PU221J R 779 RS1/10S221J R 780 RS1/10S472J R 781 RS1/10S103J R 782 RS1/10S223J R 783 RS1/10S471J R 784 RS1/10S102J R 785 RS1/10S473J R 786 RS1/10S392J R 787 RS1/10S472J R 788 RS1/10S471J R 789 RS1/10S471J R 790 RS1/10S471J R 791 RS1/10S471J R 792 RS1/10S102J R 793 RS1/10S472J R 794 RS1/10S103J R 795 RS1/16S471J R 796 RS1/16S471J R 797 RS1/16S471J R 798 RS1/16S471J R 799 RS1/10S472J R 801 RS1/10S152J R 802 RS1/10S103J R 803 RS1/10S103J R 804 RS1/10S822J R 805 RS1/10S823J R 806 RS1/10S823J R 807 RS1/10S103J R 808 RS1/10S333J R 809 RS1/10S363J R 810 RS1/10S103J R 811 RS1/4S4R7J R 812 RS1/10S102J R 814 RS1/10S394J R 815 RS1/10S274J R 817 RS1/10S472J R 818 RS1/10S104J R 819 RS1/4S4R7J R 820 RS1/10S152J R 821 RS1/10S222J R 822 RS1/10S102J R 823 RS1/10S105J R 824 RS1/10S473J R 825 RS1/10S103J R 826 RS1/10S273J R 1221 RS1/10S103J R 1222 RS1/10S103J R 1223 RS1/10S103J R 1224 RS1/10S103J R 1226 RS1/16S103J R 1227 RS1/16S242J =====Circuit Symbol and No.===Part Name Part No. --- ------ ------------------------------------------ ------------------------- =====Circuit Symbol and No.===Part Name Part No. --- ------ ------------------------------------------ ------------------------- www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 69 FH-2816ZF,2716ZF R 1228 RS1/16S101J R 1229 RS1/16S910J R 1231 RS1/16S112J R 1233 RS1/16S753J R 1235 RS1/16S0R0J R 1237 RS1/16S122J R 1239 RS1/16S753J R 1241 RS1/16S472J R 1243 RS1/16S513J R 1245 RS1/16S473J R 1247 RS1/10S113J R 1249 RS1/10S562J R 1251 RS1/10S392J R 1253 RS1/10S221J R 1255 RS1/10S752J R 1257 RS1/16S684J R 1259 RS1/16S472J R 1615 RS1/10S101J R 1616 RS1/10S103J R 1617 RS1/10S822J R 1618 RS1/10S103J R 1619 RS1/10S473J R 1620 RS1/10S182J R 1621 RS1/10S182J R 1622 RS1/10S102J R 1623 RS1/10S102J R 1631 RA4C102J R 1632 RA4C102J R 1633 RA4C102J R 1634 RA4C102J R 1635 RA4C102J R 1636 RA4C102J R 1637 RA4C682J R 1638 RA4C102J R 1640 RA4C102J R 1641 RA4C102J R 1642 RA4C222J R 1643 RA4C473J R 1644 RA4C473J R 1645 RA4C221J R 1648 RA4C102J R 1649 RS1/10S220J R 1650 RS1/16S102J R 1651 RS1/16S102J R 1652 RS1/16S102J R 1653 RS1/16S102J R 1654 RS1/10S362J R 1655 RS1/10S362J R 1656 RS1/10S473J CAPACITORS C 103 CEJANP100M16 C 104 CEJANP100M16 C 105 CEAL1R0M50 C 106 CEAL1R0M50 C 107 CEJANP100M16 C 108 CEJANP100M16 C 111 CKSQYB103K50 C 112 CKSQYB103K50 C 113 CKSQYB561K50 C 114 CKSQYB561K50 C 115 CEJANP3R3M25 C 116 CEJANP3R3M25 C 119 CKSQYB563K16 C 120 CKSQYB563K16 C 121 CEJANPR33M50 C 122 CEJANPR33M50 C 123 CEAL220M6R3 C 124 CEAL2R2M50 C 125 CKSQYB683K16 C 126 CKSQYB154K16 C 127 CEAL101M10 C 128 CEJANP100M16 C 129 CEJANP100M16 C 130 CEJANP100M16 C 131 CEJANP100M16 C 138 CEAL2R2M50 C 139 CEAL220M6R3 C 140 CKSQYB683K16 C 143 CEALNP1R0M50 C 144 CEALNP1R0M50 C 145 CEALNP1R0M50 C 146 CEALNP1R0M50 C 147 CEALNP1R0M50 C 148 CEALNP1R0M50 C 149 CEALNP1R0M50 C 150 CEALNP1R0M50 C 151 CEALNP1R0M50 C 152 CEALNP1R0M50 C 153 CEALNP1R0M50 C 154 CEALNP1R0M50 C 155 CEALNP1R0M50 C 156 CEALNP1R0M50 C 157 CEALNP1R0M50 C 158 CEALNP1R0M50 C 159 CEAL100M16 C 160 CEAL100M16 C 161 CEAL100M16 C 162 CEAL100M16 C 163 CEAL150M10 C 164 CEAL150M10 C 165 CEAL1R0M50 C 166 CEAL1R0M50 C 189 CKSQYB273K50 C 291 CKSQYB102K50 C 293 CKSYB684K16 C 295 CKSYB274K16 C 297 CKSQYB124K16 C 299 CKSQYB394K16 C 305 CKSQYB104K50 C 306 CEAL330M10 C 307 CEAL1R0M50 C 308 CEAL1R0M50 C 309 CEAL100M16 C 314 CEAL100M16 C 315 CEAL100M16 C 316 CEAL100M16 C 317 CEAL100M16 C 318 CCSQCH470J50 C 319 CCSQCH470J50 C 320 CEAL100M16 C 321 CEAL100M16 C 322 CCSQCH101J50 C 323 CEAL100M16 C 324 CEJA101M16 C 325 CEAL100M16 C 326 CEAS331M6R3 C 329 CCSQCH471J50 C 331 CCSQCH470J50 C 332 CCSQCH470J50 C 333 CCSQCH101J50 =====Circuit Symbol and No.===Part Name Part No. --- ------ ------------------------------------------ ------------------------- =====Circuit Symbol and No.===Part Name Part No. --- ------ ------------------------------------------ ------------------------- www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 70 FH-2816ZF,2716ZF C 335 CKSYB105K16 C 336 CKSYB105K16 C 337 CKSYB105K16 C 338 CKSYB105K16 C 343 CEAL220M16 C 344 CEAL220M16 C 345 CEAL100M16 C 346 CEAL4R7M16 C 347 CEAL4R7M16 C 348 CCSQCH221J50 C 349 CKSQYB103K50 C 501 CEAL100M16 C 502 CKSQYB103K50 C 504 CKSQYB223K50 C 505 CCSQCH101J50 C 506 CEAL100M16 C 507 CCSQCH101J50 C 508 CCSQCH101J50 C 509 CCSQCH101J50 C 510 CKSQYB103K50 C 511 CFTNA474J50 C 512 0.047µF/16V CCG1008 C 513 CKSQYB103K50 C 514 4.7µF/16V CCH1005 C 515 CKSQYB273K50 C 516 CKSQYB273K50 C 517 CKSQYB103K50 C 519 CKSQYB223K50 C 520 CKSQYB102K50 C 521 CCSQCH101J50 C 522 CCSQCH150J50 C 523 CCSQCH150J50 C 527 CKSQYB104K50 C 528 CCSQCH101J50 C 530 CKSYB105K16 C 531 CKSQYB104K50 C 532 CKSQYB472K50 C 533 CEAL100M16 C 534 CKSQYB223K50 C 535 CKSQYB104K50 C 536 CCSQCH101J50 C 537 CKSQYB104K50 C 538 CEAL4R7M16 C 539 CKSQYB473K50 C 540 CKSQYB102K50 C 542 CCSQCH270J50 C 543 CCSQCH270J50 C 544 CEAL1R0M50 C 545 CEAL1R0M50 C 546 CKSQYB562K50 C 547 CKSQYB562K50 C 548 CEAL330M10 C 549 CEAL2R2M50 C 550 CKSYB124K25 C 551 CKSYB124K25 C 552 CKSQYB332K50 C 553 CEAL100M16 C 554 CKSQYB103K50 C 555 CKSQYB332K50 C 556 CKSQYB332K50 C 558 CFTLA474J50 C 559 CSZA4R7K10 C 560 CSZA100M10 C 561 CFTLA474J50 C 562 CSZA2R2K16 C 563 CCSQCH510J50 C 564 CKSQYB103K50 C 565 CEAL470M10 C 566 CKSQYB332K50 C 567 CKSYB102K50 C 568 CCSQCH101J50 C 571 CEAL4R7M16 C 601 CCSQCH101J50 C 602 CCSQCH101J50 C 603 CCSQCH220J50 C 604 CCSQCH180J50 C 605 CCSQCH220J50 C 606 CCSQCH220J50 C 608 CCSQCH101J50 C 609 CCSQCH681J50 C 610 CCSQCH681J50 C 619 CEAL100M16 C 620 CEAL100M16 C 621 CEAL100M16 C 622 CCSQCH181J50 C 623 CCSQCH181J50 C 624 CASA100M6R3 C 635 CKSQYB104K16 C 636 CKSQYB473K50 C 637 CKSQYB103K50 C 645 CKSQYB102K50 C 646 CKSQYB473K50 C 651 CKSQYB103K50 C 652 CEAL1R0M50 C 653 CEAL1R0M50 C 654 CEAL101M10 C 656 CEAL100M16 C 657 CKSQYB103K50 C 659 CKSQYB103K50 C 660 CEAL2R2M50 C 661 CKSQYB472K50 C 662 CKSQYB472K50 C 663 CKSQYB104K16 C 740 CKSQYB473K50 C 741 CKSQYB473K50 C 801 4700µF/16V CCH1188 C 802 CKSQYB103K50 C 803 CKSQYB103K50 C 804 CEAS102M16 C 805 CKSQYB473K50 C 806 CEAS471M6R3 C 807 CASA100M6R3 C 808 CEAS331M10 C 809 CEAS221M10 C 810 CASA101M10 C 811 CASA470M10 C 812 CEAL101M10 C 813 CKSQYB472K50 C 814 CKSQYB103K50 C 815 CKSQYB102K50 C 816 CKSQYB102K50 C 817 CKSQYB102K50 C 818 CKSQYB102K50 C 819 CSZA220M10 C 821 CKSQYB102K50 C 822 CKSQYB102K50 C 823 CKSQYB102K50 C 824 CKSQYB102K50 C 825 CKSQYB102K50 C 826 CKSQYB102K50 C 827 CKSQYB102K50 C 828 CKSQYB102K50 C 829 0.1F/5.5V CCL1027 C 1201 CKSQYB332K50 C 1203 CKLSR563K16 C 1205 CKLSB333K50 C 1207 CEALR15M50 C 1209 CEJA221M6R3 =====Circuit Symbol and No.===Part Name Part No. --- ------ ------------------------------------------ ------------------------- =====Circuit Symbol and No.===Part Name Part No. --- ------ ------------------------------------------ ------------------------- www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 71 FH-2816ZF,2716ZF C 1213 CEAL6R8M35 C 1214 CKSQYB102K50 C 1220 CKSQYB104K16 C 1580 CKSQYB332K50 Compoud Unit Consists of EQ PCB Connector PCB VF SUB PCB Unit Number : HWM5956 Unit Name : Compound Unit MISCELLANEOUS IC 201 IC BA14741F IC 202 IC BA14741F IC 203 IC BA14741F IC 204 IC BA4558F-P IC 205 IC BA3308F IC 206 IC BA14741F IC 207 IC BA14741F IC 208 IC BA14741F IC 209 IC BA4558F-P IC 210 IC TC4066BF IC 211 IC BA3308F IC 1001 IC DS36277 IC 1051 IC NJM4558MD IC 1052 IC MC33165DW Q 201 Chip Transistor 2SA1162 Q 202 Transistor DTC114EK Q 1011 Chip Transistor 2SA1162 Q 1012 Chip Transistor 2SA1162 Q 1013 Transistor DTC124EK Q 1051 Transistor DTA124EK Q 1052 Transistor DTC143EK Q 1053 Transistor 2SC3113 Q 1054 Transistor 2SD2396 Q 1055 Transistor 2SA1428 Q 1056 Transistor 2SD1859 D 1011 Diode 1SS133 D 1012 Diode 1SS133 D 1021 Diode 1SS133 D 1022 Diode MTZ5R6J(C) D 1051 Diode MTZ6R8J(B) D 1052 Diode 1SS133 D 1053 Diode MTZ5R1J(C) D 1054 Diode ERA83-006 D 1055 Diode SC016-2 L 1051 Coil CTH1202 T 1051 Transformer CTT1067 RESISTORS R 6 RS1/10S0R0J R 7 RS1/10S0R0J R 201 RS1/10S472J R 202 RS1/10S472J R 203 RS1/10S152J R 204 RS1/10S152J R 205 RS1/10S102J R 206 RS1/10S102J R 207 RS1/10S623J R 208 RS1/10S623J R 209 RS1/10S753J R 210 RS1/10S753J R 211 RS1/10S122J R 212 RS1/10S122J R 213 RS1/10S152J R 214 RS1/10S152J R 215 RS1/10S822J R 216 RS1/10S822J R 217 RS1/10S122J R 218 RS1/10S122J R 219 RS1/10S683J R 220 RS1/10S683J R 221 RS1/10S623J R 222 RS1/10S623J R 223 RS1/10S102J R 224 RS1/10S102J R 227 RS1/10S333J R 228 RS1/10S333J R 229 RS1/10S122J R 230 RS1/10S122J R 231 RS1/10S683J R 232 RS1/16S683J R 233 RS1/10S472J R 234 RS1/10S472J R 235 RS1/10S912J R 236 RS1/10S912J R 237 RS1/10S392J R 238 RS1/10S392J R 239 RS1/10S683J R 240 RS1/10S683J R 241 RS1/10S113J R 242 RS1/10S113J R 243 RS1/10S102J R 244 RS1/10S102J R 245 RS1/10S392J R 246 RS1/10S392J R 247 RS1/10S101J R 248 RS1/10S101J R 249 RS1/10S182J R 250 RS1/10S182J R 251 RS1/10S332J R 252 RS1/10S332J R 253 RS1/10S103J R 254 RS1/10S103J R 255 RS1/10S564J R 261 RS1/10S472J R 262 RS1/10S472J R 263 RS1/10S910J R 264 RS1/10S910J R 265 RS1/10S132J R 266 RS1/10S132J R 267 RS1/10S823J R 268 RS1/10S823J R 269 RS1/10S753J R 270 RS1/10S753J R 271 RS1/10S132J R 272 RS1/10S132J R 273 RS1/10S362J R 274 RS1/10S362J R 275 RS1/10S683J R 276 RS1/10S683J R 277 RS1/10S112J R 278 RS1/10S112J R 279 RS1/10S623J R 280 RS1/10S623J R 281 RS1/10S683J R 282 RS1/10S683J R 283 RS1/10S122J R 284 RS1/10S122J R 285 RS1/10S183J R 286 RS1/10S183J R 287 RS1/16S273J R 288 RS1/10S273J R 289 RS1/10S132J R 290 RS1/10S132J =====Circuit Symbol and No.===Part Name Part No. --- ------ ------------------------------------------ ------------------------- =====Circuit Symbol and No.===Part Name Part No. --- ------ ------------------------------------------ ------------------------- E F D www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 72 FH-2816ZF,2716ZF R 291 RS1/10S753J R 292 RS1/10S753J R 293 RS1/16S472J R 294 RS1/10S472J R 295 RS1/10S622J R 296 RS1/10S622J R 297 RS1/10S242J R 298 RS1/10S242J R 299 RS1/10S433J R 300 RS1/10S433J R 1001 RS1/8S223J R 1002 RS1/8S472J R 1003 RS1/8S472J R 1004 RS1/8S472J R 1005 RS1/8S470J R 1006 RS1/8S470J R 1011 RS1/10S473J R 1012 RS1/10S472J R 1013 RS1/10S472J R 1014 RS1/10S102J R 1021 RD1/4PU103J R 1022 RD1/4PU101J R 1023 RD1/4PU221J R 1024 RS1/10S822J R 1051 RS1/10S101J R 1052 RS1/10S182J R 1053 RS1/10S103J R 1054 RS1/10S392J R 1055 RS1/10S103J R 1056 RS1/10S103J R 1057 RS1/10S822J R 1058 RS1/10S332J R 1059 RS1/10S101J R 1060 RS2PMF3R3J R 1061 RS2PMF1R8J R 1062 RS2PMF2R2J R 1063 RS2PMF2R2J R 1064 RS1/10S332J R 1065 RS1/10S472J R 1066 RS1/4S102J R 1067 RS1PMFR47J R 1068 RS1/10S333J R 1069 RS1/10S112J R 1070 RS1/10S223J R 1201 RS1/10S113J R 1202 RS1/10S113J R 1203 RS1/10S242J R 1204 RS1/10S242J R 1205 RS1/10S392J R 1206 RS1/10S392J R 1207 RS1/10S101J R 1208 RS1/10S101J R 1209 RS1/10S182J R 1210 RS1/10S182J R 1211 RS1/10S332J R 1212 RS1/10S332J R 1213 RS1/10S103J R 1214 RS1/10S103J R 1215 RS1/10S472J R 1216 RS1/10S473J R 1217 RS1/10S473J R 1218 RS1/10S564J R 1261 RS1/10S432J R 1262 RS1/10S432J R 1263 RS1/10S472J R 1264 RS1/10S472J R 1277 RS1/10S0R0J R 1278 RS1/10S0R0J CAPACITORS C 201 CEAL220M16 C 202 CEAL220M16 C 203 CEAL220M16 C 204 CEAL220M16 C 205 CKLSQB153K50 C 206 CKLSQB153K50 C 207 CKLSB393K50 C 208 CKLSB393K50 C 209 CKSQYB122K50 C 210 CKSQYB122K50 C 211 CKLSQB102K50 C 212 CKLSQB102K50 C 213 CKLSB393K50 C 214 CKLSB393K50 C 215 CKSYB274K16 C 216 CKSYB274K16 C 217 CKLSB273K50 C 218 CKLSB273K50 C 221 CKLSQB222K50 C 222 CKLSQB222K50 C 223 CKSYB682K50 C 224 CKSYB682K50 C 225 CCSQCH331J50 C 226 CCSQCH331J50 C 227 CKLSR104K16 C 228 CKLSR104K16 C 229 CKLSR104K16 C 230 CKLSR104K16 C 231 CKLSR104K16 C 232 CKLSR104K16 C 233 CEAL150M10 C 234 CEAL150M10 C 235 CEJA221M6R3 C 236 CEJA221M6R3 C 239 CKSQYB102K50 C 240 CEAL3R3M50 C 251 CKLSQB153K50 C 252 CKLSQB153K50 C 253 CKSYB153K50 C 254 CKSYB153K50 C 255 CKLSB183K50 C 256 CKLSB183K50 C 257 CKLSQB472K50 C 258 CKLSQB472K50 C 259 CKSQYB393K25 C 260 CKSQYB393K25 C 261 CKLSR104K16 C 262 CKLSR104K16 C 263 CKLSB223K50 C 264 CKLSB223K50 C 265 CKLSQB562K50 C 266 CKLSQB562K50 C 267 CKLSQB103K50 C 268 CKLSQB103K50 C 269 CCSQCH681J50 C 270 CCSQCH681J50 C 271 CCSQCH331J50 C 272 CCSQCH331J50 C 273 CKLSR104K16 C 274 CKLSR104K16 =====Circuit Symbol and No.===Part Name Part No. --- ------ ------------------------------------------ ------------------------- =====Circuit Symbol and No.===Part Name Part No. --- ------ ------------------------------------------ ------------------------- www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 73 FH-2816ZF,2716ZF C 275 CKLSR104K16 C 276 CKLSR104K16 C 277 CKLSR104K16 C 278 CKLSR104K16 C 279 CEAL150M10 C 280 CEAL150M10 C 281 CEJA221M6R3 C 282 CEJA221M6R3 C 285 CKSQYB102K50 C 286 CEAL3R3M50 C 1001 CEAL220M10 C 1002 CKSQYB222K50 C 1003 CKSQYB222K50 C 1004 CCSQCH181J50 C 1005 CCSQCH181J50 C 1011 CKSQYB223K50 C 1012 CKSQYB473K50 C 1051 CKSQYB102K50 C 1052 CKSQYB103K50 C 1053 CKSQYB562K50 C 1054 CEJA101M16 C 1056 CASA6R8M30 C 1057 CKSQYB471K50 C 1058 CKSQYB223K50 C 1059 CEAS101M50 C 1061 CEAL100M6R3 C 1071 CKSQYB332K50 C 1081 CKSQYB102K50 C 1082 CKSQYB102K50 C 1083 CKSQYB102K50 C 1223 CKLSQB272K50 C 1224 CKLSQB272K50 Unit Number : EWY1009 Unit Name : Deck Unit MISCELLANEOUS IC 251 IC HA12163 IC 351 IC PA2020A Q 271 Transistor 2SC4116 Q 351 Transistor 2SB1260 Q 352 Transistor 2SC4102 D 351 Diode MA141K VR 301 Semi-fixed 33k½(B) CCP1130 VR 302 Semi-fixed 33k½(B) CCP1130 RESISTORS R 255 RS1/16S181J R 256 RS1/16S181J R 257 RS1/16S183J R 258 RS1/16S183J R 259 RS1/16S133J R 260 RS1/16S133J R 261 RS1/16S274J R 262 RS1/16S274J R 271 RS1/16S183J R 272 RS1/8S223J R 273 RS1/8S223J R 274 RS1/8S103J R 275 RS1/16S473J R 276 RS1/16S104J R 277 RS1/16S224J R 278 RS1/16S104J R 281 RS1/8S0R0J R 282 RS1/8S0R0J R 283 RS1/8S0R0J R 284 RS1/8S0R0J R 285 RS1/16S0R0J R 286 RS1/16S0R0J R 288 RS1/16S0R0J R 289 RS1/16S0R0J R 322 RS1/8S223J R 351 RS1/16S102J R 352 RS1/16S102J R 353 RS1/16S102J R 354 RS1/16S102J R 355 RS1/10S274J R 356 RS1/10S202J R 357 RS1/10S472J R 358 RS1/10S103J R 359 RS1/10S103J R 360 RS1/10S102J R 361 RS1/10S622J R 373 RS1/8S0R0J R 374 RS1/8S0R0J R 375 RS1/8S0R0J R 401 RS1/16S273J R 402 RS1/16S223J R 403 RS1/16S274J R 404 RS1/16S823J R 405 RS1/16S274J CAPACITORS C 251 CKSRYB391K50 C 252 CKSRYB391K50 C 253 CKSRYB391K50 C 254 CKSRYB391K50 C 255 CKSRYB103K25 C 256 CKSRYB103K25 C 271 CEV1R0M50 C 272 CKSQYB104K16 C 301 CKSYB474K16 C 302 CKSYB474K16 C 309 CKSQYB104K16 C 310 CKSQYB104K16 C 351 CKSYB224K25 C 352 CKSQYB392K50 C 353 CKSQYB103K50 C 354 CKSQYB103K50 C 355 CKSYB104K50 C 356 CKSQYB103K50 C 401 CKSRYB182K50 C 402 CKSRYB822K50 C 403 CKSRYB333K16 C 404 CKSRYB471K50 Keyboard Unit Consists of Keyboard PCB Volume PCB Unit Number : HWM6008 Unit Name : Keyboard Unit MISCELLANEOUS IC 901 IC LC75725E IC 950 IC MB88307APF IC 951 IC MB88307APF Q 901 Transistor 2SC2882 Q 902 Transistor UN2111 Q 903 Transistor UN221D Q 904 Transistor UN2111 Q 905 Transistor UN221D Q 906 Transistor UN2111 Q 907 Transistor UN221D =====Circuit Symbol and No.===Part Name Part No. --- ------ ------------------------------------------ ------------------------- =====Circuit Symbol and No.===Part Name Part No. --- ------ ------------------------------------------ ------------------------- I C L www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 74 FH-2816ZF,2716ZF Q 908 Transistor 2SA1162 Q 909 Transistor UN221D Q 910 Transistor UN2111 Q 911 Transistor UN221D Q 912 Transistor UN2111 Q 913 Transistor UN221D Q 914 Transistor UN2111 Q 915 Transistor UN221D Q 916 Transistor UN2111 Q 917 Transistor UN221D Q 918 Transistor DTA124EK Q 919 Transistor DTC124EK Q 920 Transistor DTC124EK Q 952 Transistor 2SC4207 Q 953 Transistor 2SC2712 Q 954 Transistor 2SC4207 Q 955 Transistor 2SC4207 D 901 DTZ7R5(C) D 902 Chip Diode MA151WK D 903 LED CL150PGCD(AB) D 905 LED CL150PGCD(AB) D 906 LED CL150PGCD(AB) D 907 LED CL150PGCD(AB) D 908 Diode DTZ2R0(A) D 909 LED CL150PGCD(AB) D 910 LED CL150PGCD(AB) D 911 LED CL150PGCD(AB) D 912 Diode DTZ2R0(A) D 913 Diode DTZ2R0(A) D 914 Diode DTZ2R0(A) D 950 LED CL150PGCD(AB) D 951 LED CL150PGCD(AB) D 952 LED CL150PGCD(AB) D 953 LED CL150PGCD(AB) D 954 LED CL150PGCD(AB) D 955 LED CL150PGCD(AB) D 956 LED CL150PGCD(AB) D 957 LED CL150PGCD(AB) D 958 LED CL150PGCD(AB) D 959 LED CL150PGCD(AB) D 960 LED CL150PGCD(AB) D 961 LED CL150PGCD(AB) D 962 LED CL150PGCD(AB) D 963 LED CL150PGCD(AB) D 964 LED CL150PGCD(AB) D 965 LED CL150PGCD(AB) D 966 LED CL150PGCD(AB) D 967 LED CL150PGCD(AB) D 968 LED CL150PGCD(AB) D 969 LED CL150PGCD(AB) D 970 LED CL150PGCD(AB) D 971 LED CL150PGCD(AB) D 974 LED CL150PGCD(AB) D 975 LED CL150PGCD(AB) D 976 LED CL150PGCD(AB) D 977 LED CL150PGCD(AB) D 978 LED CL150PGCD(AB) D 979 LED CL150PGCD(AB) D 981 LED CL150PGCD(AB) D 982 LED CL150PGCD(AB) D 983 LED CL150PGCD(AB) D 984 LED CL150PGCD(AB) D 985 LED CL150PGCD(AB) D 989 Diode DTZ2R0(A) D 990 Diode DTZ2R0(A) D 991 Diode DTZ2R0(A) D 992 Diode DTZ2R0(A) D 993 Diode DTZ2R0(A) D 996 Diode DTZ2R0(A) D 998 Diode DTZ2R0(A) D 999 Diode DTZ2R0(A) VR 901 Encoder HSD1033 VF HAW1359 RESISTORS R 901 RS1/10S562J R 902 RS1/4S121J R 903 RS1/10S103J R 904 RS1/4S103J R 905 RS1/10S393J R 906 RS1/8S222J R 907 RS1/8S222J R 908 RS1/8S222J R 909 RS1/8S222J R 910 RS1/10S103J R 911 RS1/10S103J R 912 RS1/8S222J R 913 RS1/8S222J R 914 RS1/8S222J R 915 RS1/8S222J R 916 RS1/8S223J R 917 RS1/8S181J R 918 RS1/8S151J R 919 RS1/8S201J R 920 RS1/10S103J R 921 RS1/10S103J R 922 RS1/10S103J R 923 RS1/10S103J R 924 RS1/10S103J R 925 RS1/10S103J R 926 RS1/10S103J R 927 RS1/10S103J R 928 RS1/8S201J R 929 RS1/8S201J R 930 RS1/16S393J R 931 RS1/16S393J R 932 RS1/16S393J R 933 RS1/16S393J R 934 RS1/16S393J R 935 RS1/16S393J R 936 RS1/16S393J R 937 RS1/16S393J R 938 RS1/16S393J R 939 RS1/16S393J R 940 RS1/16S393J R 941 RS1/16S393J R 942 RS1/16S393J R 943 RS1/16S393J R 944 RS1/16S393J R 945 RS1/16S393J R 946 RS1/16S393J R 947 RS1/16S393J R 948 RS1/16S393J R 949 RS1/16S393J R 950 RS1/8S201J R 951 RS1/8S201J R 952 RS1/8S201J R 953 RS1/8S201J R 954 RS1/8S161J R 955 RS1/8S161J =====Circuit Symbol and No.===Part Name Part No. --- ------ ------------------------------------------ ------------------------- =====Circuit Symbol and No.===Part Name Part No. --- ------ ------------------------------------------ ------------------------- www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 75 FH-2816ZF,2716ZF R 956 RS1/8S161J R 957 RS1/8S161J R 958 RS1/8S271J R 959 RS1/8S271J R 960 RS1/8S201J R 961 RS1/10S102J R 962 RS1/8S201J R 963 RS1/8S181J R 964 RS1/8S181J R 965 RS1/10S472J R 966 RS1/8S151J R 967 RS1/10S331J R 968 RS1/8S151J R 969 RS1/8S151J R 970 RS1/8S151J R 971 RS1/8S151J R 972 RS1/8S151J R 973 RS1/8S181J R 974 RS1/4S121J R 975 RS1/10S473J R 976 RS1/16S393J R 977 RS1/16S393J R 978 RS1/16S393J R 979 RS1/16S393J R 980 RS1/10S103J R 981 RS1/10S103J R 982 RS1/10S103J R 983 RS1/10S562J R 984 RA3C472J R 985 RS1/10S153J R 986 RS1/10S153J R 987 RS1/16S472J R 988 RS1/16S472J R 989 RS1/4S103J R 991 RS1/16S393J R 994 RS1/16S393J R 995 RS1/16S393J R 996 RS1/16S393J R 997 RS1/16S393J R 998 RS1/16S393J R 999 RS1/16S393J R 1901 RS1/16S471J R 1902 RS1/16S471J R 1903 RS1/10S471J R 1904 RS1/10S471J CAPACITORS C 901 CCSQCH220J50 C 902 CKSQYB103K50 C 903 CKSQYB103K50 C 904 CKSQYB102K50 C 905 CKSQYB104K16 C 906 CKSQYB102K50 C 907 CKSQYB102K50 C 908 CKSQYB104K16 C 909 CCSQCH101J50 C 910 CKSQYB102K50 Unit Number : CWX2188 Unit Name : Photo Unit MISCELLANEOUS Q 1 Photo-transistor CPT-230S-X Q 2 Photo-transistor CPT-230S-X Unit Number : Unit Name : PCB Unit S 1 Switch (Load) ESG1004 S 2 Switch (70µS) ESG1004 EGN 1 Photo-Interrupter EGN1005 L 1 Inductor ETM0001 R 1 Resistor RD1/4HM181J Unit Number : Unit Name : Reel PCB EGN 2 Photo-reflector EGN1004 EGN 3 Photo-reflector EGN1004 Miscellaneous Parts List Pickup Unit (Service) CXX1232 M 1 Motor Unit (Spindle) CXA9101 M 2 CRG Motor Unit (Carriage) CXA8986 M 3 Load Motor Unit (Loading) CXA8702 M 1 Motor Unit (Main) EXA1381 M 2 Motor Unit (Sub) EXA1382 HD 1 Head Assy EXA1488 C 1 CEA4R7M35LS2 =====Circuit Symbol and No.===Part Name Part No. --- ------ ------------------------------------------ ------------------------- =====Circuit Symbol and No.===Part Name Part No. --- ------ ------------------------------------------ ------------------------- H J K www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 76 FH-2816ZF,2716ZF ·Note : Unlike previous CD mechanism modules the grating angle of the PU unit cannot be adjusted after the PU unit is changed. The PU unit in the CD mechanism module is adjusted on the production line to match the CD mechanism module and is thus the best adjusted PU unit for the CD mechanism module. Changing the PU unit is thus best considered as a last resort. However, if the PU unit must be changed, the grating should be checked using the procedure below. ·Purpose : To check that the grating is within an acceptable range. ·Symptoms of Mal-adjustment : If the grating is off by a large amount symptoms such as being unable to close tracking, being unable to perform track search operations, or track searching taking a long time, may appear. ·Method : ·Measuring Equipment ·Oscilloscope, Two L.P.F. ·Measuring Points ·E, F, REFOUT ·Disc ·ABEX TCD-784 ·Mode ·TEST MODE ·Checking Procedure 1. In test mode, load the disc and switch the 5V regulator on. 2. Using the FF and REV buttons, move the PU unit to the innermost track. 3. Press key 4 to close focus, the display should read "91". Press key 3 to implement the tracking balance adjustment the display should now read "81". Press key 4 4 times. The display will change, returning to "81" on the fourth press. 4. As shown in the diagram above, monitor the LPF outputs using the oscilloscope and check that the phase difference is within 75° . Refer to the photographs supplied to determine the phase angle. 5. If the phase difference is determined to be greater than 75° try changing the PU unit to see if there is any improvement. If, after trying this a number of times, the grating angle does not become less than 75° then the mechanism should be judged to be at fault. ·Note Because of eccentricity in the disc and a slight misalignment of the clamping center the grating waveform may be seen to "wobble" ( the phase difference changes as the disc rotates). The angle specified above indicates the average angle. ·Hint Reloading the disc changes the clamp position and may decrease the "wobble". 6. ADJUSTMENT 6.1 CHECKING THE GRATING - Checking the Grating After Changing the Pickup Unit(Service) 100kW 390pF 100kW 390pF E REFOUT F REFOUT Xch Ych L.P.F. L.P.F. Oscilloscope CONTROL UNIT www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 77 FH-2816ZF,2716ZF 45° 0° 75° 60° 30° 90° Grating waveform Ech ® Xch 20mV/div, AC Fch ® Ych 20mV/div, AC www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 78 FH-2816ZF,2716ZF 6.2 TUNER/AUDIO ADJUSTMENT - Connection Diagram FM SSG Stereo Modulator 50½(37.5½) Antenna Plug Dummy Antenna 50½(75½) MOTHER UNIT TUNER UNIT +13.2V Antenna Jack DC Regulated Power Supply 4k½ 4k½ mV Meter (1) Oscilloscope VR302 (R) VR301 (L) R L mV Meter(2) Pin2 Pin3 CN251 DECK UNIT DC V Meter(1) Center Meter Pin 19 TUNER UNIT (BOTTOM VIEW) C63 TUNER UNIT (TOP VIEW) L2 L5 T31 Pin1 Pin13 Pin14 Pin26 L4 L52 VR156 DECK UNIT GND ACC VR154 VR101 L52 VR151 BACKUP GGD1157 Pin28 Pin27 DC V Meter(2) Pin 6 GND TC1 T231 DC V Meter(3) Pin 20 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 79 FH-2816ZF,2716ZF Resistance Voltage NULL Short 0 VOL DN 73.2W 1.34 VOL UP 206.2W 2.54 NEXT 443.2W 3.45 MODE 896.2W 4.09 NULL(for SWL) 4812.2W 4.80 not SWL OPEN 5.00(AVDD) Resistance(x)W Voltage NULL Short 0 VOL DN 75W 1.36 VOL UP 205W 2.53 NEXT 445W 3.45 MODE 915W 4.10 NULL(for SWL) 4815W 4.80 not SWL OPEN 5.00(AVDD) - How to check control without using the steering remote control unit Schematic diagram of Ford Actual Schematic diagram 0.5V 1.94V 3.00V 3.77V 4.45V 4.90V 5.00V Change the resistance value of XW as shown in the table to check the voltage value of V. FM ADJUSTMENT NOTE:Before proceeding to further adjustments after switching power ON, let the tuner run for ten minutes to allow the circuits to stabilize. Modulation M1 : MONO MOD., 400Hz, 100%(75kHz Dev.) M2 : MONO MOD., 400Hz, 30%(22.5kHz Dev.) S : STEREO MOD., 400Hz, L or R=100%(67.5+7.5kHz Dev.) FM SSG Displayed Adjustment Adjustment Method No. Frequency(MHz) Level(dBµ) Frequency(MHz) Point (Switch Position) TUN Volt 1 ••••• ••••• 108.0 L5 DC V Meter(1) : 6.5V Center 1 98.1 M1 60–80 98.1 L52 Center Meter : 0 IFT 1 98.1 M1 0–10 98.1 T31 mV Meter(1) : Maximum ANT 1 89.9 M1 0–10 89.9 L2 mV Meter(1) : Maximum RF 1 89.9 M1 0–10 89.9 L4 mV Meter(1) : Maximum Image 1 129.3 M1 55–75 107.9 TC1 mV Meter(1) : Minimum Sepa- 1 98.1 S 60 98.1 VR101 mV Meter(1) : Separation ration Maximum (STEREO MODE) ARC 1 98.1 S 40 98.1 VR154 mV Meter(1) : Separation6dB Separation (STEREO MODE) Inter- 1 98.1 M1 60 98.1 ••••• mV Meter(1) : AdB station 2 98.1 M1 –¥ 98.1 VR151 mV Meter(1) : A–35dB Noise Search 1 98.1 M2 36 98.1 VR156 DC V Meter(2) : More than 3.5V 2 98.1 M2 35 98.1 VR156 DC V Meter(2) : 0V 3 98.1 M2 36 98.1 ••••• DC V Meter(2) : More than 3.5V AM ADJUSTMENT FM SSG Displayed Adjustment Adjustment Method No. Frequency(kHz) Level(dBµ) Frequency(kHz) Point (Switch Position) TUN Volt 1 ••••• ••••• 1710 T231 DC V Meter(3) DOLBY B NR ADJUSTMENT No. Test Tape Adjustment Point Adjustment Method (Switch Position) 1 NCT-150 VR301(Lch),VR302(Rch) mV Meter(2) : –8.24dBs(300mV)±1.0dB (400Hz,200nwb/m) (DOLBY NR Switch : OFF) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 80 FH-2816ZF,2716ZF - Checking the Auto Volume Control - Set to AVC3 and increase pulses to confirm that the sound level increases. (Set duty to 50%) - Input vehicle-speed pulse to Pin 1 of J1 mentioned on page 96. Set Pin 2 to grounding. Perform measurement. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 81 FH-2816ZF,2716ZF 7. GENERAL INFORMATION 7.1 PARTS 7.1.1 IC 1 3 2 OUT1 -IN1 +IN1 GND +IN2 -IN2 OUT2 VCC 4 5 6 7 8 + + BA4558F-P TAB P-GND2 OUT2(-) ST-BY OUT2(+) VCC OUT1(-) P-GND1 OUT1(+) SVR IN1 IN2 S-GND IN4 IN3 AC-GND OUT3(+) P-GND3 OUT3(-) VCC OUT4(+) MUTE OUT4(-) P-GND4 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 TDA7384 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 82 FH-2816ZF,2716ZF *PD6181A 19 20 32 33 51 52 64 1 - Pin Functions (PD6181A) Pin No. Pin Name I/O Format Function and Operation 1 PCK O N PLL communications clock output 2 PDO O N PLL communications data output 3 PDI I PLL communications data input 4 SL I Signal level input 5 NL I Noise level input 6 TRGL Connect to pulldown 7 SOUND Audio signal input for identification of identical plogram 8 RMUTE O N RDS mute output 9-11 OPEN O N L output 12 AVCC 5V power supply input 13 AVR 5V power supply input 14 AVSS Connect to GND 15 IRSEL µ COM select input 16 RCK I RDS recovery modulation clock input 17 RDT I RDS recovery modulation data input 18 LDET PLL lock detection input 19 RDSLK I RDSLK signal input 20 IRRST I µ COM reset input 21 MOD0 Connect to GND 22 MOD1 Connect to GND 23 Xin I Oscillator input 24 Xout O C Oscillator output 25 VSS Connect to GND 26 DRST O C Decoder reset output 27 L/S O C Noise level sensitivity select output 28 CURRQ O C PLL-TV-Fix output 29 IRRDY O C Communications ready output 30 RECIVE O C OPEN 31 CORR O C OPEN 32 ERROR O C OPEN 33 NC O C OPEN 34-38 NC I OPEN 39 DK I OPEN 40 SK I OPEN 41 MUTCNT I OPEN 42-49 NC I OPEN 50 VSS Connect to GND 51 TEST I Test program input 52 IRCK Communications clock input 53 IRDO C Communications data output 54 IRDI Communications data input 55 PCE O C PLL communication enable output 56 GD O C Tuner unit gate drive control output 57 VCC 5V power supply input 58 SD I SD signal input 59 MDSENS I Modulation detector input 60-64 NC O N OPEN Format Meaning C C MOS N N channel open drain IC's marked by* are MOS type. Be careful in handling them because they are very liable to be damaged by electrostatic induction. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 83 FH-2816ZF,2716ZF - Pin Functions(PD4692D) Pin No. Pin Name I/O Format Function and Operation 1 RMUTE I Rear mute 2 MUTE O C Mute 3 M/s O C Fix main or sub antenna for diagnosis 4 AVSS GND 5,6 NC Not used 7 AVREF1 VDD 8 ARXD I ACP-BUS receive pin 9 ATXD O ACP-BUS trans pin 10 NC Not used 11 RDSSTI I RDS microcomputer serial data input pin 12 RDSSTO O RDS microcomputer serial data output pin 13 rdsck RDS microcomputer serial clock pin 14 EDTI I NVRAM data input pin 15 brxen I/O RX enabled pin 16 bsrq I Request output pin 17 BDATA I/O P-BUS serial data input/output pin 18 bsck P-BUS serial clock pin 19 brst O C P-BUS reset pin 20 SYSPW O C System power 21 EVCK O C NVRAM. EVOL clock output 22 EVDT1 O C NVRAM. EVOL1 data output 23 DJPSEL0 O C cd?dj PHONE audio select 0 (Front) 24 NC Not used 25 ECE O C NVRAM Chip enable 26 MUTE O C System mute 27-29 NC I/O C Not used 30 PSW I/O C Power sense 31 CLOCK I/O C CLOCK 32 NC Not used 33 VSS GND 34,35 NC Not used 36 kst) O N Key strobe 0 37 kst! O N Key strobe 1 38 kst@ O N Key strobe 2 39 kst# O N Key strobe 3 40 RDSSEL O C RDS mother select pin 41 rdsrst O C RDS mother reset pin 42 rdsen O C RDS mother enable pin 43 SUBMUTE I 44 PCE O C PLL (LC72146) IC chip enable 45 PCK O C PLL (LC72146) IC clock output 46 PDO I PLL (LC72146) IC data output 47 PDI O C PLL (LC72146) IC data input 48 VST O C EVOL strobe pin 49 VDT2/PCL O C EVOL2 data output/PCL output 50 SD I SD input 51 TEST/TEN I Test mode/Test mode enable 52-58 kd)-kd^ I Key return 0-6 59 S/m I S/m 60 reset I Reset 61 SPEED I Speed pulse input 62 pta I PHONE WAKE-UP input 63 bsens I BACK UP sense 64 asens I ACC sense 65 SWDET I Activate sub-woofer check for diagnosis 66 acpint I ACP-BUS interrupt edge input 67 ROTINT I Rotary encoder interrupt edge input 68 VDD Microcomputer power supply 69 X2 Oscillator output (4.9152MHz) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 84 FH-2816ZF,2716ZF *PD4692D 80 1 20 21 40 41 60 61 Format Meaning C C MOS N N channel open drain Pin No. Pin Name I/O Format Function and Operation 70 X1 Oscillator input (4.9152MHz) 71 IC Connect to GND 72 XT2 Sub clock oscillator output (32.768KHz) 73 XT1 Sub clock oscillator input (32.768KHz) 74 AVDD I A/D converter analog power supply 75 AVREF0 I A/D converter reference voltage input 76 SL I SL level input 77 ASYSON O C Last source ON/OFF output 78 RSPSW O C Rear speaker vol!·VOL2 output select SW 79 ROTIN0 I Rotary encoder pulse input 0 80 ROTIN1 I Rotary encoder pulse input 1 - Pin Functions(PD4693D) Pin No. Pin Name I/O Format Function and Operation 1 NC Not used 2 VFCE O C VF driver chip enable 3 vfblk O C VF driver inhibit port 4 AVSS Connect to GND 5 ILMOUT O Illumination D/A output 6 NC Not used 7 AVREF1 I Connect to VDD 8 ILM2 I Illumination input sense 9 VFDT O C VF driver data output 10 VFCK O C VF driver clock input/output 11 XSI I C CD LSI serial data input 12 XSO O C CD LSI serial data output 13 xsck O C CD LSI serial clock output 14 NC Not used 15 brxen I/O C P-BUS receive input/output 16 bsrq I P-BUS communication request input (TSI) 17 BSIO I/O C P-BUS communication serial data input/output (TSO) 18 bsck I/O C P-BUS communication serial clock input/output (TSCK) 19 xrst O C CD LSI reset output 20 XAO O C Control signal disting uishing data from microcomputer 21 xstb O C CD LSI strobe output 22 VDCNT O C VD (CD module power supply) control 23 CD5VON O C CD 5V power supply control 24 CONT O C Servo driver power control 25 CDLOAD O C Load motor load control output 26 CDEJECT O C Load motor eject control output 27 cdmute O C CD mute output 28 home I C Homeposition detector input 29 clamp I C Disc clamp sense input 30 FOK I C FOK signal input 31 MIRR I C Mirror detector input 32 LOCK I C Spindle lock detector input www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 85 FH-2816ZF,2716ZF Pin No. Pin Name I/O Format Function and Operation 33 VSS Connect to GND 34 CSEL O C CD compression output 35 PHONE I C Phone button illumination output 36 ADCLK O N External A/D convertor serial clock 37 ADDO O N External A/D convertor serial data output 38 ADDI I N External A/D convertor serial data input 39 ADCS O N External A/D convertor chip selector 40 xst O C Extended I/O strobe output 41 XDT O C Extended I/O data output 42 XCK O C Extended I/O clock output 43 TAPPW O C Tape power supply control 44 F/R O C Normal/Reverse output 45 PEE1 O C Not used 46 PLAY O C MS filter output 47 NR O C Noise reduction output 48 SC2 O C Sub motor control 2 output 49 SC1 O C Sub motor control 1 output 50 CM O C Capstan motor control 51 stby O C Mecha standby control 52 MSIN I C Curved pulse input 53 mtl I C Cassette mechanism METAL detector input 54 CSLOAD I C Cassette mechanism Loading detector input 55 POS I C Cassette mechanism position sense input 56 RES I C Cassette mechanism reverse end sense input 57 NES I C Cassette mechanism normal end sense input 58 DMUTE O C Cassette mute pin 59 PEE2 O C Not used 60 reset I Reset 61 NC Connect to GND 62 ilm2 I C Illumination input sense 63 brst I C P-BUS reset input 64 bsens I C B. up Sense 65 cdej I C CD EJECT switch input 66 csej I C Cassette EJECT switch input 67 NC Not used 68 VDD Microcomputer power supply 69 X2 Oscilltor output 70 X1 Oscilltor input 71 IC Connect to GND 72 XT2 OPEN 73 TEST I Test mode/test mode enable 74 AVDD A/D converter analog power supply 75 AVREF0 I A/D converter reference voltage input 76 DSCSNS I Disc detect input 77 EJTSNS I Disc EJECT sense input 78 TEMP I Temperature detector 79 VDSENS I VD overvoltage, ground-fault sensing input 80 ADPW O C Analog power supply control Format Meaning C C MOS N N channel open drain 80 1 20 21 40 41 60 61 *PD4693D www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 86 FH-2816ZF,2716ZF 1 2 3 4 5 6 7 8 9 10 11 12 24 23 22 21 20 18 17 16 15 14 F I N OUT2 RNF GND OUT1 VM VCC FIN POWER SAVE RIN VREF F I N 19 13 POWER SAVE CONTROL LOGIC TSD BA6997FP 1 R 2 3 4 D 5 6 7 8 RO RE DE DI Vcc DO/RI DO/RI GND DS36277 1 3 2 4 7 6 5 GND 14 13 12 11 10 9 8 + VCC + + + BA14741F www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 87 FH-2816ZF,2716ZF MC33165DW 8 0.25V OSC LOGIC and THERMAL SHAT DOWN 7 + 6 5 4 3 2 1 + 9 10 11 12 13 14 15 16 + lpkSENSE Vcc OSCILLATED FREQUENCY SELECT CAPACITOR VOLTAGE FEEDBACK 1 VOLTAGE FEEDBACK 2 LVI OUTPUT GND GND SWITCH COLLECTOR DRIVER · COLLECTOR SWITCH EMITTER BOOTSTRAP INPUT 7.0V 2.0mA 60 VFB 1.25V 15K 1.125V 45K LIMIT LVI LC75725E 48 47 46 45 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 49 50 51 52 53 54 55 56 VFL G1 G2 G3 G4 G5 G6 G7 G8 G9 G10 G11 VFL S43 S42 S41 64 63 62 61 57 58 59 ADDRESS DETECTOR SHIFT REGISTER GRID CONTROL DIMMER TIMING GENERATOR CLOCK GENERATOR TIMING GENERATOR DRIVER LATCH MPX 60 DIGIT DRIVER SEGMENT DRIVER 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 44 43 42 41 40 39 38 37 36 35 34 33 S8 S7 S6 S5 S4 S3 S2 S1 VSS OSCO OSCI VDD BLK CE CL DI S25 S26 S27 S28 S29 S30 S31 S32 S33 S34 S35 S36 S37 S38 S39 S40 S9 S10 S11 S12 S13 S14 S15 S16 S17 S18 S19 S20 S21 S22 S23 S24 SHIFT REGISTER(8) 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 LATCH(8) DRIVER(8) 8 8 SO LOAD O0 O1 O2 O3 SC/SC VSS VCC RESET SI O7 O6 O5 O4 OE LSB MSB MB88307APF www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 88 FH-2816ZF,2716ZF 7.1.2 DISPLAY - VF(HAW1359) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 89 FH-2816ZF,2716ZF 7.2 DIAGNOSIS 7.2.1 FUNCTION 1 2 3 4 5 6 7 8 DIAGNOSTICS RUN B and A(BODY and ASSEMBLY) TEST AUDIO SUBSYSTEM SELF-TEST VIEW AUDIO SUBSYSTEM SELF-TEST RESULT VIEW DTC’S CLEAR DTC’S RUN SIGNAL STRENGTH TEST VIEW SOFTWARE CONFIGURATION LEVEL RUN DISPLAY TEST DIAGNOSTICS (This function is only work in TUNER mode) D No. FUNCTION KEY TRIGGER NOTE Start DIAGNOSTICS mode by pressing 1-24, 1-27 at the same time more than 1 Sec. to less than 5 Sec. -CONTENTS OF DIAGNOSTICS- RADIO SELF-TEST SPEAKER WALK-AROUND TEST HIDDEN ANTENNA TEST SUBWOOFER TEST CDDJ COMMUNICATION TEST Start AUDIO SUBSYSTEM SELF-TEST by 1-22 during B and A TEST or other DIAGNOSTICS In case that error is found ,error is stored as DTC (DIAGNOSTICS TROUBLE CODES) In case that error is stored as DTC , after finish SELF-TEST. SCROLL stored DTC by 1-6 , 1-7 During B and A test or other DIAGNOSTICS TEST, display DTC by 1-23. Then SCROLL DTC by 1-6 , 1-7 While display DTC, CLEAR DTC by 1-15 or 1-18 more than 1 Sec. During B and A test or other DIAGNOSTICS TEST, display the SIGNAL STRENGTH of the currently tuned frequency by 1-24 During B and A test or other DIAGNOSTICS TEST, display SOFTWARE CONFIGURATION LEVEL(VERSION) by 1-25 During B and A test or other DIAGNOSTICS TEST, radio illuminates all elements of VFD for 5 Sec. by 1-26 VALID IN TUNER MODE *1 *1 *1 *1 *1 *2 - - - - - - - - *1 RADIO SELF-TEST : Confirm whether the CHECK SUM of inner memory of m-COM (and so on) is normal or not. SPEAKER WALK-AROUND TEST: Output TUNER SOUND from each speaker in turn for 5 Sec.(in order to check the CAR WIRING) HIDDEN ANTENNA TEST : Start TUNER SEEK. If RADIO found the station, output from speakers for 2 Sec. SUBWOOFER TEST : Output TUNER SOUND from subwoofer for 1.5 Sec. CDDJ COMMUNICATION TEST : Display whether CDDJ is connected or not. *2 AUDIO SUBSYSTEM SELF-TEST : Confirm the RESULT of RADIO SELF-TEST included *1 and whether the equipment which communicate on ACP network are connected with RADIO or not. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 90 FH-2816ZF,2716ZF 7.2.2 DISASSEMBLY - Removing the Case(Not shown) 1. Insert and turn a flat screwdriver to remove the case. - Removing the Grille Assy and Keyboard Unit 1. Press the four tabs and Disconnect the connector indicated by arrow and then removing the Grille Assy. 2. Removing the Knob Unit. 3. Removing the five screws and then removeving the Keyboard Unit. CAUTION: Remove the Knob Unit before removing the screws that secure the Keyboard Unit. Do not hold CN901 by hand when removing the Keyboard Unit from the grille. Be careful not to bend the connector teeth when installing the grille to the product. Be sure to insert the insulator into the Grille Assy. - Removing the Heat Sink 1. Removing the five screws and then removing the Heat Sink. - Removing the CD Mechanism Module and Chassis Unit 1. Removing the four screws A. 2. Disconnect the connector and then removing the CD Mechanism Module. 3. Removing the six screws B and then removing the Chasis Unit. CAUTION: Plug the Fuji Card into the card connector of the CD mechanism or main unit at an angle of 60 degrees. A B A B B B B B A A Keyboard Unit Knob Unit Grille Assy Heat Sink CD Mechanism Module Chassis Unit www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 91 FH-2816ZF,2716ZF - Removing the Cassette Mechanism Module 1. Removing the four screws. 2. Disconnect the connector and then removing the Cassette Mechanism Module. - Removing the Mother Unit 1. Removing the five screws. 2. Unbend the tabs at four locations and then removing the Mother Unit. Mother Unit Cassette Mechanism Module www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 92 FH-2816ZF,2716ZF 1)Precautions · This unit uses a single power supply (+5V) for the regulator. The signal reference potential, therefore, is connected to REFO(approx. 2.5V) instead of GND. If REFO and GND are connected to each other by mistake during adjustments, not only will it be impossible to measure the potential correctly, but the servo will malfunction and a severe shock will be applied to the pick-up. To avoid this, take special note of the following. Do not connect the negative probe of the measuring equipment to REFO and GND together. It is especially important not to connect the channel 1 negative probe of the oscilloscope to REFO with the channel 2 negative probe connected to GND. Since the frame of the measuring instrument is usually at the same potential as the negative probe, change the frame of the measuring instrument to floating status. If by accident REFO comes in contact with GND, immediately switch the regulator or power OFF. · Always make sure the regulator is OFF when connecting and disconnecting the various filters and wiring required for measurements. · Before proceeding to further adjustments and measurements after switching regulator ON, let the player run for about one minute to allow the circuits to stabilize. · Since the protective systems in the unit's software are rendered inoperative in test mode, be very careful to avoid mechanical and /or electrical shocks to the system when making adjustment. · Test mode starting procedure Switch ACC, back-up ON while pressing the 1 and 3 keys together. · Test mode cancellation Switch ACC, back-up OFF. · Disc detection during loading and eject operations is performed by means of a photo transistor in this unit.Consequently, if the inside of the unit is exposed to a strong light source when the outer casing is removed for repairs or adjustment, the following malfunctions may occur. *During PLAY, even if the eject button is pressed,the disc will not be ejected and the unit will remain in the PLAY mode. *The unit will not load a disc. When the unit malfunctions this way, either re- position the light source, move the unit or cover the photo transistor. · When loading and unloading discs during adjustment procedures, always wait for the disc to be properly clamped or ejected before pressing another key. Otherwise, there is a risk of the actuator being destroyed. · Turn power off when pressing the button TRACK UP or the button TRACK DOWN key for focus search in the test mode. (Or else lens may stick and the actuator may be damaged.) · SINGLE/4TRK/10TRK/32TRK will continue to operate even after the key is released.Tracking is closed the moment C-MOVE is released. · JUMP MODE resets to SINGLE as soon as power is switched OFF. 7.2.3 TEST MODE - CD TESTMODE www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 93 FH-2816ZF,2716ZF Rough Servo Normal focus close CRG Move 100TR JUMP Only Single TR/4TR/10TR/32TR/100TR CD Carriage move or T. jump During regulatoruoff, press the 3 key and the system will be put into the new test mode COMP Power OFF AGC *1 Carriage move or T. jump *2 *1 S curve check Focus EQ check *2 *3 SHUF SHUF Power ON (in the case of continuous jumping) SCAN Display 00(99) 01 02 CD multi player selected Single 91(81) 10TRK 93(83) 32TRK 94(84) C.MOVE 96(86) 4TRK 92(82) 100TRK 95(85) *1 Display example Power OFF Power OFF Power OFF T.JUMP MODE select 00 00' 00" 91 91' 91" *4 Normal display *5 Focus cancel Tracking offset Tracking balance C 01 03' 33" 3 *1 99 99' 99" 4 Back-up ON 6 4 COMP COMP COMP COMP 4 FF REV SCAN SHUF 4 FF REV SCAN 4 3 REV FF SHUF 3 Adjustment for T.OFFSET Not adjustment for T.OFFSET *4 *2 MIN,SEC(or Thack No.) *4 F.AGC Gain T.AGC Gain F.Bias Display Display Display Display Display - Flow Chart www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 94 FH-2816ZF,2716ZF - Error Number Indication If the CD should fail to operate or if an error has taken place during operation the player will enter into the error mode, and the cause of the error will be numerically indicated. This is aimed at assisting in analysis or repair. (1) Basic Means of Display · With ERROR indicated in "MODE" on IP-BUS Display data, an error code is transmitted by the use of MIN and SEC. The MIN and SEC data will be identical. ·Examples of DisplayEr XX (2) Error Codes Error Classification Description Cause/Detail Code 10 ELECTRIC Carriage home failure Carriage doesn't move to or from the innermost position ®Home switch failed and/or carriage immobile 11 ELECTRIC Focus failure Focus failed ®Defects, disc upside-down, severe vibration 12 ELECTRIC SETUP failure Spindle failed to lock or subcode unreadable Subcode failure ®Spindle defective, defect, severe vibration 14 ELECTRIC Mirror failure Unrecorded CD-ROM The disc is upside-down, defects, vibration 17 ELECTRIC Set up failure AGC protect failed ®Defects, disc upside-down, severe vibration 30 ELECTRIC Search time out Failed to reach target address ®Carriage/tracking defective and/or defects A0 SYSTEM Power failure Power overvoltage or short circuit detected ®Switching transistor defective and/or power abnormal "defects" means scratches, dirt etc an the surface of the disc. - Single CD Player New Test Mode(aging operation and setup analysis) The single CD player plays in normal mode. After being set up, it will display FOK (focus), LOCK (spindle), subcode, sound skip, protection against a mechanical error or the like, occurrence of an error, cause and time of an expiry, if any, (and disk number) During the setup, the CD software operation status (internal RAM and C-point)is displayed. (1) How to enter NEW TEST Mode See the test mode flow chart Page 93. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 95 FH-2816ZF,2716ZF (2) Relations of keys between TEST and NEW TEST Modes Keys Test Mode New Test Mode Regulator OFF Regulator ON PLAY in progress Error Occurred, Protection Activated 5 Regulator ON Regulator OFF ¾ Time of occurrence / cause of error select TRACK UP ¾ FWD-Kick TRACK UP / FF ¾ TRACK ¾ REV-Kick TRACK ¾ DOWN DOWN /REV 3 ¾ Tracking close SCAN ¾ 4 ¾ Tracking open MODE ¾ 1 ¾ Focus close ¾ ¾ SCAN To New Test Focus Mode AUTO/MANU ¾ Mode Select Operations,such as EJECT, CD ON/OFF, etc. are performed normally (3) Error Cause (Error Number) Code Error Code Classification Mode Description Cause Detail 40 ELECTRIC PLAY FOK=L Put out of focus Scratch, 41 ELECTRIC PLAY LOCK=L 150ms Spindle unlock Stain, 42 ELECTRIC PLAY Subcode Failed to read subcode Vibration, unacceptable 500ms Servo defect, 43 ELECTRIC PLAY Sound skipped Last address memory etc... operated (4) Indicating an Operation Status During Setup Status No. Description Protection operation 01 Carriage home mode started None 02 Carriage moving inwards 10-second time out, Home switch failed 03 Carriage moving outwards 10-second time out, Home switch failed 05 Carriage moving outwards None 11 Setup started None 12 Spindle turn/Focus search started None 13 Waiting for focus closure (XSI=L) Failure to close focus 10,14 Waiting for focus closure (FOK=H) Failure to close focus 15, 16, 17 Focus closed, Tracking open Focus disrupted 18 During focus AGC Focus disrupted Subcode waiting 19 During tracking AGC Disrupted focus 20 Waiting for MIRR, LOCK or subcode read Focus disrupted, MIRR NG, Failure to lock, Carriage closed, SPINDLE=ADAPTIVE failed to read subcode 5) Example of Display. ·SET UP in progress · Operation (PLAY, SEARCH, etc.) in progress perfectly identical with that in the normal mode. · Protection/Error upon occurrence (a) Error number indicated Select the display with the (b) Track number and 5 key. absolute time indicated TNo. 11 Min 11 Sec 11 Er xx TNo. 10 Min 40 Sec 05 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 96 FH-2816ZF,2716ZF J2 FUNCTION PIN# 1 ILLUM(+) J1 2 ILLUM(-) 3 START 4 CLOCK 5 RR(+) 6 RR(-) 7 8 9 RF(+) RF(-) 10 11 12 13 V.BATTERY(+) RUN/ACCY. RADIO GND LR(+) LR(-) 14 15 16 LF(+) LF(-) PW AMP GND FUNCTION PIN# FUNCTION PIN# 1 SW AUDIO(-) SW AUDIO(+) 2 SW AUDIO SHLD 3 SW E/CLD J2 4 5 6 7 8 N.C. N.C. N.C. N.C. 1 2 3 4 5 6 7 8 9 N.C. PW ANTENNA SCP(+) SCP(-) ASYSON ACP A ACP B N.C. SPEED INPUT 10 11 12 13 14 PTA(PHONE) MONO(-) MONO(+) MONO SHLD SWC1 15 16 17 N.C. CDDJ SHLD CDDJR(+) CDDJR(-) 18 CDDJL(+) CDDJL(-) 19 20 J3 J4 MAIN ANTENNA JACK SUB ANTENNA JACK J3 J1 8 5 4 1 20 14 13 8 7 1 16 9 1 8 7.2.4 CONNECTOR FUNCTION DESCRIPTION -FH-2816ZF/X1H/UC www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 97 FH-2816ZF,2716ZF www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 98 FH-2816ZF,2716ZF A B G I J K H 7.3 BLOCK DIAGRAM - FH-2816ZF/X1H/UC www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 99 FH-2816ZF,2716ZF C F L D E www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 100 FH-2816ZF,2716ZF 8. OPERATIONS AND SPECIFICATIONS 8.1 OPERATIONS - RADIO - CD POWER SWITCH/ VOLUME TUNER BUTTON AM/FM AUTO SEEK MANUAL SEEK UPSCAN PRESET RECALL AUTOSET POWER SWITCH/ VOLUME TUNER BUTTON AM/FM Tr SEARCH COMPRESSION ON/OFF CD BUTTON FAST REWIND SCAN/ DISC SCAN FAST FORWARD SHUFFLE ON/OFF CD EJECT www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 101 FH-2816ZF,2716ZF - TAPE POWER SWITCH/ VOLUME Cuing REW FF SIDE CHANGE Dolby B NR EJECT TAPE BUTTON - CD MULTI POWER SWITCH/ VOLUME Tr SEARCH COMPRESSION ON/OFF CD BUTTON FAST REWIND SCAN/ DISC SCAN FAST FORWARD SHUFFLE ON/OFF CD EJECT DISC CHANGE www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com FH-2816ZF,2716ZF 8.3 SPECIFICATIONS Power source.......................14.4 V(10.5-15.9 V allowable) Grounding system........................................Negative type Dimensions.........................188(W) X 103(H) X 180(D)mm Weight ........................................................................2.6 Kg Maximum power output..17.5 W X 4 (4 W, THD 10 %, 1 kHz) Load impedance..............................................................4W CD player System ...................................Compact disc audio system Usable discs................................Compact disc (8 / 12 cm) Signal format ....................Sampling frequency : 44.1 kHz .............................Number of guantization bits: 16 ; linear Signal-to-noise ratio........................................68 dB ± 5dB Distortion....................................................Less than 0.2 % Cassette player Tape................................Compact cassette tape(C30-C90) Tape speed ...4.76cm / sec.(+0.14cm / sec.,-0.05cm / sec.) Wow and flutter..........................Less than 0.2 % (WRMS) Cross talk........................................................60 dB ± 10dB Stereo separation................................................50 ± 10dB Signal-to-noise ratio (Dolby B out)....................................................52 dB ± 5dB FM tuner Frequency range ....................................87.75 - 107.9 MHz Usable sensitivity ........6 dBm ± 8 dB(mono, S / N : 30 dB) Signal-to-noise ratio.......................................62 dB ± 6 dB Distortion.......................................................Less than 2 % Stereo separation...............................................35 ± 10 dB AM tuner Frequency range..........................................530 - 1710 kHz Usable sensitivity...............................................30 ± 5 dBµ Signal-to-noise ratio........................................50 dB ±6 dB Stereo separation...............................30 dB ±15 dB(1 kHz) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com
