ORDER NO. PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A. PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936 PIONEER CORPORATION 2004 DEH-2700/XU/UC CRT3363 HIGH POWER CD PLAYER WITH FM/AM TUNER DEH-2700/XU/UC This service manual should be used together with the following manual(s): Model No. Order No. Mech.Module Remarks CX-3110 CRT3178 S10.1 CD Mech. Module : Circuit Description, Mech. Description, Disassembly For details, refer to "Important Check Points for Good Servicing". K-ZZA. NOV. 2004 Printed in Japan www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-2700/XU/UC 2 1 2 3 4 1 2 3 4 C D F A B E SAFETY INFORMATION CAUTION This service manual is intended for qualified service technicians; it is not meant for the casual do-it-yourselfer. Qualified technicians have the necessary test equipment and tools, and have been trained to properly and safely repair complex products such as those covered by this manual. Improperly performed repairs can adversely affect the safety and reliability of the product and may void the warranty. If you are not qualified to perform the repair of this product properly and safely, you should not risk trying to do so and refer the repair to a qualified service technician. WARNING This product contains lead in solder and certain electrical parts contain chemicals which are known to the state of California to cause cancer, birth defects or other reproductive harm. Health & Safety Code Section 25249.6 - Proposition 65 - Service Precaution 1. You should conform to the regulations governing the product (safety, radio and noise, and other regulations), and should keep the safety during servicing by following the safety instructions described in this manual. 2. Before disassembling the unit, be sure to turn off the power. Unplugging and plugging the connectors during power-on mode may damage the ICs inside the unit. 3. To protect the pickup unit from electrostatic discharge during servicing, take an appropriate treatment (shorting-solder) by referring to "the DISASSEMBLY". 4. After replacing the pickup unit, be sure to check the grating. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-2700/XU/UC 3 5 6 7 8 5 6 7 8 C D F A B E [Important Check Points for Good Servicing] In this manual, procedures that must be performed during repairs are marked with the below symbol. Please be sure to confirm and follow these procedures. 1. Product safety Please conform to product regulations (such as safety and radiation regulations), and maintain a safe servicing environment by following the safety instructions described in this manual. 1 Use specified parts for repair. Use genuine parts. Be sure to use important parts for safety. 2 Do not perform modifications without proper instructions. Please follow the specified safety methods when modification(addition/change of parts) is required due to interferences such as radio/TV interference and foreign noise. 3 Make sure the soldering of repaired locations is properly performed. When you solder while repairing, please be sure that there are no cold solder and other debris. Soldering should be finished with the proper quantity. (Refer to the example) 4 Make sure the screws are tightly fastened. Please be sure that all screws are fastened, and that there are no loose screws. 5 Make sure each connectors are correctly inserted. Please be sure that all connectors are inserted, and that there are no imperfect insertion. 6 Make sure the wiring cables are set to their original state. Please replace the wiring and cables to the original state after repairs. In addition, be sure that there are no pinched wires, etc. 7 Make sure screws and soldering scraps do not remain inside the product. Please check that neither solder debris nor screws remain inside the product. 8 There should be no semi-broken wires, scratches, melting, etc. on the coating of the power cord. Damaged power cords may lead to fire accidents, so please be sure that there are no damages. If you find a damaged power cord, please exchange it with a suitable one. 9 There should be no spark traces or similar marks on the power plug. When spark traces or similar marks are found on the power supply plug, please check the connection and advise on secure connections and suitable usage. Please exchange the power cord if necessary. 0 Safe environment should be secured during servicing. When you perform repairs, please pay attention to static electricity, furniture, household articles, etc. in order to prevent injuries. Please pay attention to your surroundings and repair safely. 2. Adjustments To keep the original performance of the products, optimum adjustments and confirmation of characteristics within specification. Adjustments should be performed in accordance with the procedures/instructions described in this manual. 4. Cleaning For parts that require cleaning, such as optical pickups, tape deck heads, lenses and mirrors used in projection monitors, proper cleaning should be performed to restore their performances. 3. Lubricants, Glues, and Replacement parts Use grease and adhesives that are equal to the specified substance. Make sure the proper amount is applied. 5. Shipping mode and Shipping screws To protect products from damages or failures during transit, the shipping mode should be set or the shipping screws should be installed before shipment. Please be sure to follow this method especially if it is specified in this manual. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-2700/XU/UC 4 1 2 3 4 1 2 3 4 C D F A B E CONTENTS SAFETY INFORMATION..................................................................................................................................... 2 1. SPECIFICATIONS ............................................................................................................................................ 5 2. EXPLODED VIEWS AND PARTS LIST ............................................................................................................ 6 2.1 PACKING ................................................................................................................................................... 6 2.2 EXTERIOR................................................................................................................................................. 8 2.3 CD MECHANISM MODULE..................................................................................................................... 10 3. BLOCK DIAGRAM AND SCHEMATIC DIAGRAM.......................................................................................... 12 3.1 BLOCK DIAGRAM ................................................................................................................................... 12 3.2 OVERALL CONNECTION DIAGRAM(GUIDE PAGE).............................................................................. 14 3.3 KEYBOARD UNIT.................................................................................................................................... 20 3.4 CD MECHANISM MODULE..................................................................................................................... 22 4. PCB CONNECTION DIAGRAM ..................................................................................................................... 26 4.1 TUNER AMP UNIT................................................................................................................................... 26 4.2 KEYBOARD UNIT.................................................................................................................................... 30 4.3 CD CORE UNIT(S10) .............................................................................................................................. 32 5. ELECTRICAL PARTS LIST ............................................................................................................................ 34 6. ADJUSTMENT ............................................................................................................................................... 38 6.1 CD ADJUSTMENT................................................................................................................................... 38 6.2 CHECKING THE GRATING AFTER CHANGING THE PICKUP UNIT .................................................... 40 6.3 ERROR MODE ........................................................................................................................................ 42 6.4 SYSTEM MICROCOMPUTER TEST PROGRAM ................................................................................... 43 7. GENERAL INFORMATION............................................................................................................................. 44 7.1 DIAGNOSIS ............................................................................................................................................. 44 7.1.1 DISASSEMBLY ..................................................................................................................................... 44 7.1.2 CONNECTOR FUNCTION DESCRIPTION.......................................................................................... 47 7.2 PARTS...................................................................................................................................................... 48 7.2.1 IC .......................................................................................................................................................... 48 7.2.2 DISPLAY ............................................................................................................................................... 52 7.3 OPERATIONAL FLOW CHART ............................................................................................................... 53 7.4 CLEANING............................................................................................................................................... 54 8. OPERATIONS ................................................................................................................................................ 55 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-2700/XU/UC 5 5 6 7 8 5 6 7 8 C D F A B E 1. SPECIFICATIONS www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-2700/XU/UC 6 1 2 3 4 1 2 3 4 C D F A B E 2. EXPLODED VIEWS AND PARTS LIST 2.1 PACKING NOTES : • Parts marked by " * " are generally unavailable because they are not in our Master Spare Parts List. • The > mark found on some component parts indicatesthe importance of the safety factor of the part. Therefore, when replacing, be sure to use parts of identical designation. • Screw adjacent to mark on the product are used for disassembly. • For the applying amount of lobricants or glue, follow the instructions in this manual. (In the case of no amount instructions,apply as you think it appropriate.) " 15 11 12 13 16 1 6 10 9 8 7 5 4 2 17 3 14 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-2700/XU/UC 7 5 6 7 8 5 6 7 8 C D F A B E PACKING SECTION PARTS LIST Owner's Manual,Installation Manual Mark No. Description Part No. 1 Accessory Assy CEA4610 2 Screw Assy CEA4611 3 Fixing Screw(M2x4) CBA1488 4 Screw CBA1650 * 5 Polyethylene Bag CEG-127 6 Screw CRZ50P090FTC 7 Screw TRZ50P080FTC * 8 Polyethylene Bag CEG-158 9 Handle CNC5395 10 Bush CNV3930 11 Polyethylene Bag CEG1173 12 Carton YHG5028 13 Contain Box YHL5028 14 Protector XHP7004 15 Protector XHP7003 16-1 Owner's Manual YRD5013 16-2 Installation Manual YRD5017 16-3 Caution Card CRP1294 16-4 Caution Card CRP1310 * 16-5 Card ARY1048 17 Cord Assy XDE7008 Mark No. Description Part No. Part No. Language YRD5013 English, French, Spanish YRD5017 English, French, Spanish www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-2700/XU/UC 8 1 2 3 4 1 2 3 4 C D F A B E 2.2 EXTERIOR C C B A A B A B 33 43 53 42 35 36 37 32 2 3 2 2 14 5 15 54 4 4 4 7 12 2 34 39 41 38 49 40 48 47 46 50 52 44 31 31 10 65 66 61 60 62 57 64 63 56 59 65 65 55 58 31 31 6 9 8 19 70 29 18 26 21 20 22 24 25 23 28 27 67 68 17 17 30 45 13 51 11 16 1 68 69 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-2700/XU/UC 9 5 6 7 8 5 6 7 8 C D F A B E EXTERIOR SECTION PARTS LIST Mark No. Description Part No. 1 Screw BMZ40P140FTC 2 Screw BSZ26P060FTC 3 Screw BSZ30P060FTC 4 Screw BSZ30P200FTC 5 Cable CDE7113 6 Case CNB2793 7 Holder CNC8659 8 Earth Plate CNC8915 9 Cushion CNM8890 10 Panel CNS8046 11 Holder CNV7619 12 CD Mechanism Module(S10) CXK5601 13 Cord Assy XDE7008 14 Insulator XNM7106 15 Insulator YNM5012 16 Tuner Amp Unit YWM5049 17 Screw ASZ26P060FTC 18 Screw BPZ26P080FTC 19 Screw BSZ26P160FTC > 20 Fuse(10A) CEK1208 21 Pin Jack(CN352) CKB1057 22 Plug(CN901) CKM1376 23 Connector(CN721) CKS3835 24 Connector(CN621) CKS4124 25 Connector(CN831) CKS4944 26 Antenna Jack(CN401) CKX1056 27 Holder CND1328 28 Heat Sink CNR1668 29 Holder CND1054 30 Holder YNC5002 31 Screw BPZ20P100FZK 32 Spring CBH2210 33 Knob(VOLUME) YAA5001 34 Button(DETACH) YAC5027 35 Button(SOURCE) YAC5030 36 Button(1-6, LOCAL/BSM) YAC5031 37 Button(AUDIO, LOUDNESS) YAC5032 38 Button(BAND) YAC5033 39 Button(EJECT, PAUSE) YAC5034 40 Button(DOWN, RIGHT) YAC5035 41 Button(UP, LEFT) YAC5036 42 Button(CLOCK, EQ) YAC5039 43 Spring YBL5001 44 Cover YNS5038 45 Connector(CN1801) CKS4943 46 Sheet CNM7932 47 Connector CNV7369 48 LCD(LCD1801) YAW5021 49 Holder YNC5005 50 Lighting Conductor YNV5004 51 Lighting Conductor YNV5005 52 Rubber Contact YNV5006 53 Grille Unit YXA5071 54 Chassis Unit YXA5080 55 Button(DETACH) CAC4836 56 Spring CBH1835 57 Spring CBH2208 58 Spring CBH2367 59 Bracket CNC6791 60 Holder CNC8042 61 Cover CNM6276 62 Arm CNV4692 63 Arm CNV4728 64 Arm CNV5576 65 Screw IMS20P030FZK 66 Panel YNS5046 67 IC(IC921) NJM2388F84 68 Transistor(Q911, 991) 2SD2396 69 IC(IC302) TDA7386 70 FM/AM Tuner Unit(Z401) CWE1646 Mark No. Description Part No. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-2700/XU/UC 10 1 2 3 4 1 2 3 4 C D F A B E 2.3 CD MECHANISM MODULE A D H L M N O Q R A B C D E F G H I J K L M N O Q B 16 25 13 83 42 68 28 82 4 71 23 J K 38 23 59 87 86 5 13 34 5 5 13 44 5 C 52 53 36 4 73 29 51 18 64 76 50 10 72 75 49 77 67 27 78 60 90 48 8 17 46 6 60 11 89 43 70 14 31 65 85 66 85 31 35 14 74 85 1 2 3 R 91 12 33 61 63 21 79 57 58 62 80 13 4 86 I 45 28 7 24 47 P 41 20 40 69 39 30 P 19 56 F E 22 81 15 G 26 5 54 37 55 93 92 10 C 1GEM1024 2GEM1045 3GEM1035 1 1 1 1 1 1 1 1 2 2 2 2 1 1 1 1 1 2 2 1 3 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-2700/XU/UC 11 5 6 7 8 5 6 7 8 C D F A B E CD MECHANISM MODULE SECTION PARTS LIST Mark No. Description Part No. 1 CD Core Unit(S10) CWX3110 2 Connector(CN101) CKS4182 3 Connector(CN701) CKS4188 4 Screw BMZ20P035FTC 5 Screw BSZ20P040FTC 6 Screw(M2x4) CBA1362 7 Screw(M2x3) CBA1824 8 Screw(M2x3) CBA1825 9 ••••• 10 Washer CBF1038 11 Washer CBF1060 12 Spring CBH2390 13 Spring CBH2606 14 Spring CBH2607 15 Spring CBH2608 16 Spring CBH2609 17 Spring CBH2610 18 Spring CBH2735 19 Spring CBH2612 20 Spring CBH2613 21 Spring CBH2614 22 Spring CBH2615 23 Spring CBH2616 24 Spring CBH2617 25 Spring CBH2620 26 Spring CBH2621 27 Spring CBH2641 28 Spring CBH2642 29 Spring CBH2643 30 Spring CBH2659 31 Spring CBH2688 32 ••••• 33 Shaft CLA4441 34 Frame CND2443 35 Frame CNC9963 36 Bracket CND2712 37 Bracket CND1895 38 Arm CNC9968 39 Arm CND1909 40 Lever CND2032 41 Lever CNC9984 42 Sheet CNM8134 43 Collar CNV8447 44 Guide CNV8448 45 Arm CNV8403 46 Rack CNV8374 47 Holder CNV8376 48 Holder CNV8377 49 Arm CNV8378 50 Gear CNV8379 51 Gear CNV8380 52 Gear CNV8381 53 Gear CNV8382 54 Gear CNV8383 55 Gear CNV8384 56 Rack CNV8385 57 Arm CNV8386 58 Arm CNV8387 59 Guide CNV8388 60 Roller CNV8189 61 Gear CNV8389 62 Arm CNV8391 63 Arm CNV8390 64 Arm CNV8392 65 Damper CNV7313 66 Damper CNV7314 67 Arm CNV8394 68 Arm CNV8395 69 Guide CNV8396 70 Guide CNV8397 71 Holder CNV8398 72 Arm CNV8402 73 Gear CNV8400 74 Damper CNV7618 75 Motor Unit(M1) CXC4440 76 Chassis Unit CXC2318 77 Screw Unit CXB8729 78 Gear Unit CXC2397 79 Arm Unit CXC2316 80 Arm CND1896 81 Arm CND1894 82 Motor Unit(M2) CXB8933 83 Bracket CNC9985 84 ••••• 85 Screw(M2x5) EBA1028 86 Screw JFZ20P020FTC 87 Screw JGZ17P022FTC 88 ••••• 89 Washer YE20FTC 90 Pickup Unit(P10)(Service) CXX1647 91 Screw IMS26P030FTC 92 Spring CBL1635 93 Clamper CNV8372 Mark No. Description Part No. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-2700/XU/UC 12 1 2 3 4 1 2 3 4 C D F A B E 3. BLOCK DIAGRAM AND SCHEMATIC DIAGRAM 3.1 BLOCK DIAGRAM CN701 CN101 Q101 M LASER DIODE MONITOR DIODE HOME X201 12EJ 8EJ DSCSNS FOCUS ACT. SPINDLE MOTOR M CARRIAGE MOTOR LOADING/ TRACKING ACT. LD+ MD FOP TOP 14 5 4 1 PICKUP UNIT (P10)(SERVICE) HOLOGRAM UNIT IC 301 BA5835FP IC 201 UPD63712AGC IC 701 NJM2391DL1-33 3.3V REGULATOR SERVO CONTROL, DSP, LPF, DAC ACT,MOTOR DRIVER 1 VD VD 3R3V 7 CONT 5 LOEJ 6 DSCSNS 8 LOUT TOP FOP 16 SOP 15 SOM 17 LCOM 18 LCOP 22 1 LOEJ 23 20 LOUT XTAL xtal 24 9 CONT 12 FOP FD, TD, SD, MD AC, F, E, BD 1 LD 2 PD 42 LIMIT 3 13 TOP D CD CORE UNIT(S10) C 2 16 SO 12 XSI 3R3V 2 E TUN L 3 CDL SYSTEM IC P CN401 1 2 CN721 TUNER AMP UNIT CD L A TUN 3.3V SYS 8V VDD ANTENNA FM/AM TUNER UNIT 16 IC 721 TC7SET08FU 29 28 XSI 79 DSCSNS CDLOEJ CONT 4 2 XSI/BSI CONT/NC LOEJ/NC DSCSENS 14 6 16 17 15 B.UP 78 5 4 3 41 5 Q991 VDSENS VDCONT/BRSQ VDSENS 20 21 Q992 FMRF ANT adj RF adj FM ANT T51 CF52 CF51 RFGND OSCGND DGND AUDIOGND NC VCC VDD_3.3 3.3V 2.5V IC 4 3.3V 2.5V ← IC 2 2.5V WC CE2 ROM_VDD SL DI CK CE1 NC DO NC NC NC NC 7 6 13 5 10 9 8 11 14 18 19 20 21 1 3 2 12 15 22 16 4 17 IC 1 3.3V AM ANT FMRF ATT LPF OSC IC 3 EEPROM 5.0V IC 5 5V 3.3V ← ATT MIXER, IF AMP DET, FM MPX 24 23 Rch Lch www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-2700/XU/UC 13 5 6 7 8 5 6 7 8 C D F A B E 11 R Lch IN1-L IN2-L 2 IC 151 PML003AM ELECTRONIC VOLUME/ SOURCE SELECTOR TUN L 3 CDL 10 F Lch IC 1801 PD6340A LCD DRIVER/ KEY CONTROLLER KEY DATA LCD1801 KEY MATRIX 60 BSENS ASENS VDD B.UP 63 64 48 MUTE 21 3 5 FL- FL+ RL- RL+ B. REM ACC RLIN 12 22 4 POWER AMP IC 601(1/2) PE5462A SYSTEM CONTROLLER WIRED REMOTE CONTROL REAR OUTPUT IC 601(2/2) PE5462A IC 961 S-80834CNY IC 302 TDA7386 VDD Q911 Q931 SYSPW SYSPW VDD SWVDD STBY MUTE 3 5 CN1801 CN831 Q801 KEYBOARD UNIT VCK, VDT, VST 6 7 43 SYSPW Q452 Q453 MUTE B.UP Q821 18 20 DPDT KYDT MUTE SYSTEM CONTROLLER VDD REGULATOR BACKUP SENSE ACC SENSE B CN901 CN621 TUNPCE1 TUNPCE2 TUNPDI KEY2 STRKEY RESET TUNPDO 56 55 11 46 80 12 TUNPCK 13 TUNPDO TU 3.3V TUN 3V REG. IC 921 NJM2388F84 B.UP SYS 8V REG. IC 551 TPD1018F B. REMOTE POWER TUNPDI CE1 CE2 TUNPCK Q912 DALMON 32 B.UP 8V 20 4 8 10 9 3 5 6 7 4 8 10 9 SOURCE VOLUME LAMP IL1801 SWVDD SWVDD SRC DSENS ILM ROT1 ROT0 DPDT KYDT S1827 SWVDD 21 SOURCE 66 DSENSE 65 ILMPW 22 ROT1 36 ROT0 35 DPDT 9 KYDT 8 R Lch CN352 2 1 2 3 FLIN 14 IC 981 BA33BC0FP Q822 DSENSE SOURCE SWVDD BSENS ASENS X1 X2 70 X601 12.58291MHz 69 XO XI 21 X1801 5MHz 22 Q352 RESET 23 FL- FL+ RL- RL+ 3 9 11 12 10 1 6 3 9 11 12 10 1 6 2 2 BACK UP GND FUSE 10A ACC B. REM 16 29 28 79 XSI/BSI CONT/NC LOEJ/NC DSCSENS 78 41 VDCONT/BRSQ VDSENS www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-2700/XU/UC 14 1 2 3 4 1 2 3 4 C D F A B E 3.2 OVERALL CONNECTION DIAGRAM(GUIDE PAGE) Symbol indicates a resistor. No differentiation is made between chip resistors and discrete resistors. NOTE : Symbol indicates a capacitor. No differentiation is made between chip capacitors and discrete capacitors. The > mark found on some component parts indicates the importance of the safety factor of the part. Therefore, when replacing, be sure to use parts of identical designation. For resistors and capacitors in the circuit diagrams, their resistance values or capacitance values are expressed in codes: Ex. *Resistors Code Practical value 123 12k ohms 103 10k ohms B CN1801 C CN701 FM/AM TUNER UNIT SYSTEM CONTROLLER ANTENNA *Capacitors Code Practical value 103 0.01uF 101/10 100uF/10V FM:-19.5dBs AM: -30dBs CD:+0.35dBs E.VOL. 12.58291MHz asens bsens dsens source swvdd A-a A-b A-a A-b A-b A-a Large size SCH diagram Guide page Detailed page Note: When ordering service parts, be sure to refer to " EXPLODED VIEWS AND PARTS LIST" or "ELECTRICAL PARTS LIST". A-a Awww. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-2700/XU/UC 15 5 6 7 8 5 6 7 8 C D F A B E 3300/16 3A CEK1286 600µH TDA7386(45W) > A TUNER AMP UNIT ER CEK1208 10A > REAR L CH REAR R CH FM: +3.6dBs AM: -6.9dBs CD:+10.45dBs E.VOL. asens bsens dsens source FM: +29.6dBs AM: +19.1dBs CD:+36.45dBs WIRED REMOTE CONTROL A-b A www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-2700/XU/UC 16 1 2 3 4 1 2 3 4 C D F A B E A-a A-b A-a A-a A-b 1 2 C CN701 SYSTEM CONTROLLER FM:-19.5dBs AM: -30dBs CD:+0.35dBs E.VOL. 12.58291MHz asens bsens dsens source www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-2700/XU/UC 17 5 6 7 8 5 6 7 8 C D F A B E Symbol indicates a resistor. No differentiation is made between chip resistors and discrete resistors. NOTE : Symbol indicates a capacitor. No differentiation is made between chip capacitors and discrete capacitors. A-a A-b A-a A-a A-b 3 The > mark found on some component parts indicates the importance of the safety factor of the part. Therefore, when replacing, be sure to use parts of identical designation. For resistors and capacitors in the circuit diagrams, their resistance values or capacitance values are expressed in codes: Ex. *Resistors Code Practical value 123 12k ohms 103 10k ohms B CN1801 FM/AM TUNER UNIT SYSTEM CONTROLLER ANTENNA *Capacitors Code Practical value 103 0.01uF 101/10 100uF/10V FM:-19.5dBs AM: -30dBs asens bsens dsens source swvdd www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-2700/XU/UC 18 1 2 3 4 1 2 3 4 C D F A B E A-a A-b A-b 1 2 3300/16 3A CEK1286 TDA7386(45W) > A TUNER AMP UNIT REAR L CH REAR R CH FM: +3.6dBs AM: -6.9dBs CD:+10.45dBs . FM: +29.6dBs AM: +19.1dBs CD:+36.45dBs www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-2700/XU/UC 19 5 6 7 8 5 6 7 8 C D F A B E A-a A-b A-b 3 600µH CEK1208 10A > WIRED REMOTE CONTROL www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-2700/XU/UC 20 1 2 3 4 1 2 3 4 C D F A B E 3.3 KEYBOARD UNIT B YAW5021 5MHz www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-2700/XU/UC 21 5 6 7 8 5 6 7 8 C D F A B E B 40mA,14V A CN831 B KEYBOARD UNIT www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-2700/XU/UC 22 1 2 3 4 1 2 3 4 C D F A B E 3.4 CD MECHANISM MODULE C PICKUP UNIT(P10)(SERVICE) M1 CXC4440 SPINDLE MOTOR M2 CXB8933 LOADING/CARRIAGE MOTOR 3.3V REGULATOR MOTOR DRIVER F F F F T T T T F F T T T F S C F F T T S S C C S S C C T T F F T T F F 1 7 8 3 6 5 @ 9 0 ! # www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-2700/XU/UC 23 5 6 7 8 5 6 7 8 C D F A B E C 7.5V 7.5V SWITCHES: CD CORE UNIT(S10) S901:HOME SWITCH..........ON-OFF S903:DSCSNS SWITCH......ON-OFF S904:12EJ SWITCH.............ON-OFF S905:8EJ SWITCH...............ON-OFF The underlined indicates the switch position. CD CORE UNIT(S10) C A CN721 RF AMP / SERVO / DSP DAC / LPF F SIGNAL LINE FOCUS SERVO LINE TRACKING SERVO LINE CARRIAGE SERVO LINE SPINDLE SERVO LINE T C S S C T F C C 3 6 5 @ $% 4 2 9 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-2700/XU/UC 24 1 2 3 4 1 2 3 4 C D F A B E - Waveforms Note : 1. The encircled numbers denote measuring points in the circuit diagram. 2. Reference voltage REFO1(1.65V) 1 DSCSNS 2 CLCONT 3 LOEJ 4 VD 5V/div 5V/div 5V/div 10V/div 500ms/div When loading a 12cm CD Ref.: GND Mode: Normal 5 SIN 6 CIN 7 TIN 1V/div 500mV/div 500mV/div 2s/div When setting up after loading a 12cm CD-DA disc Ref.: REFO Mode: Normal 1 DSCSNS 2 CLCONT 3 LOEJ 4 VD 5V/div 5V/div 5V/div 10V/div 500ms/div When loading an 8cm CD Ref.: GND Mode: Normal @ MDX 5 SIN 500mV/div 1V/div 5ms/div Spindle waveform during "Play" Ref.: REFO Mode: Normal # RFAGC 500mV/div 0.5µs/div Ref.: REFO Mode: Normal @ MDX 5 SIN 500mV/div 1V/div 5µs/div Spindle waveform during "Play"(Magnified) RF eye pattern Ref.: REFO Mode: Normal 8 FIN ! FE 500mV/div 500mV/div 200ms/div Focus Search Ref.: REFO Mode: TEST # RFAGC 0 TE 7 TIN 1V/div 500mV/div 500mV/div 500µs/div Ref.: REFO Mode: TEST 0 TE # RFAGC 500mV/div 500mV/div 2ms/div When "Tracking Open" 1 Track Jump Ref.: REFO Mode: TEST 8 FIN 9 RFOK 5 SIN 200mV/div 2V/div 2V/div 500ms/div When setting up "Source On"(12cm CD-DA) During "Play"(CD-DA) Ref.: REFO Mode: Normal ! FE 8 FIN 0 TE 7 TIN 500mV/div 500mV/div 500mV/div 500mV/div 20ms/div Ref.: REFO Mode: Normal 0 TE ! FE 500mV/div 500mV/div 200ms/div When setting up "Source On" Ref.: REFO Mode: Normal www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-2700/XU/UC 25 5 6 7 8 5 6 7 8 C D F A B E # RFAGC 0 TE 7 TIN 1V/div 500mV/div 500mV/div 500ms/div 32 Track Jump Ref.: REFO Mode: TEST # RFAGC 7 TIN 0 TE 8 FIN 1V/div 1V/div 1V/div 1V/div 500µs/div Ref.: REFO Mode: Normal # RFAGC 0 TE 7 TIN 1V/div 500mV/div 500mV/div 5ms/div 100(32x3) Track Jump When reproducing black dots(1mm) Ref.: REFO Mode: TEST $ LOUT % ROUT 1V/div 1V/div 200µs/div Analog Audio Ref.: AGND Mode: Normal 1 DSCSNS 2 CLCONT 3 LOEJ 5V/div 5V/div 5V/div 200ms/div Ref.: GND Mode: Normal 1 DSCSNS 2 CLCONT 3 LOEJ 5V/div 5V/div 5V/div 200ms/div When "Eject"(12cm CD) When "Eject"(8cm CD) Ref.: GND Mode: Normal # RFAGC 0 TE 6 CIN 5 SIN 1V/div 1V/div 500mV/div 2V/div 500µs/div When reproducing scratch(1mm) During inside/outside search (outer circumference → inner circumference) Ref.: REFO Mode: Normal # RFAGC 0 TE 6 CIN 5 SIN 1V/div 1V/div 500mV/div 2V/div 500µs/div Ref.: REFO Mode: Normal # RFAGC 0 TE 6 CIN 5 SIN 1V/div 1V/div 500mV/div 2V/div 5ms/div When reproducing fingerprint(65µm) Ref.: REFO Mode: Normal www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-2700/XU/UC 26 1 2 3 4 1 2 3 4 C D F A B E 4. PCB CONNECTION DIAGRAM 4.1 TUNER AMP UNIT Capacitor Connector P.C.Board Chip Part A A TUNER AMP UNIT SIDE B SIDE A NOTE FOR PCB DIAGRAMS 1.The parts mounted on this PCB include all necessary parts for several destination. For further information for respective destinations, be sure to check with the schematic dia- gram. 2.Viewpoint of PCB diagrams C CN701 CORD ASSY WIRED REMOTE CONTROL 1 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 2 3 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-2700/XU/UC 27 5 6 7 8 5 6 7 8 C D F A B E A SIDE A B CN1801 FRONT RCA ANTENNA FM/AM TUNER UNIT SSY 0 11 12 13 14 15 1 4 2 2 1 3 16 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-2700/XU/UC 28 1 2 3 4 1 2 3 4 C D F A B E A A TUNER AMP UNIT PCL TEST 1 1 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-2700/XU/UC 29 5 6 7 8 5 6 7 8 C D F A B E A SIDE B PCL EST 1 1 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-2700/XU/UC 30 1 2 3 4 1 2 3 4 C D F A B E 4.2 KEYBOARD UNIT B B KEYBOARD UNIT SIDE A CLOCK EQ VOLUME SOURCE 1 2 BAND LCD1801 4 3 6 LOCAL/BSM 5 DOWN LOUDNESS PAUSE RIGHT LEFT AUDIO EJECT UP www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-2700/XU/UC 31 5 6 7 8 5 6 7 8 C D F A B E B B KEYBOARD UNIT SIDE B A CN831 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-2700/XU/UC 32 1 2 3 4 1 2 3 4 C D F A B E 4.3 CD CORE UNIT(S10) C C CD CORE UNIT(S10) SIDE A A CN721 PICKUP UNIT(P10)(SERVICE) M2 LOADING /CARRIAGE MOTOR M1 SPINDLE MOTOR E REFO1 F HOME www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-2700/XU/UC 33 5 6 7 8 5 6 7 8 C D F A B E C C CD CORE UNIT(S10) SIDE B 12EJ 8EJ DSCSNS 3 2 1 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-2700/XU/UC 34 1 2 3 4 1 2 3 4 C D F A B E 5. ELECTRICAL PARTS LIST NOTE: • Parts whose parts numbers are omitted are subject to being not supplied. • The part numbers shown below indicate chip components. Chip Resistor RS1/_S___J,RS1/__S___J Chip Capacitor (except for CQS.....) CKS....., CCS....., CSZS..... • The > mark found on some component parts indicatesthe importance of the safety factor of the part. Therefore, when replacing, be sure to use parts of identical designation. Circuit Symbol and No. Part No. A Unit Number:YWM5049 Unit Name:Tuner Amp Unit MISCELLANEOUS IC 151 (B,132,80) IC PML003AM IC 302 (A,93,132) IC TDA7386 IC 551 (B,70,94) IC TPD1018F IC 601 (B,85,52) IC PE5462A IC 721 (B,45,20) IC TC7SET08FU IC 921 (A,6,119) IC NJM2388F84 IC 961 (A,46,62) IC S-80834CNY IC 981 (B,146,27) IC BA33BC0FP Q 352 (B,159,125) Transistor IMH3A Q 452 (B,140,115) Transistor DTC124EU Q 453 (B,135,107) Transistor DTA124EU Q 801 (B,28,25) Transistor 2SA1036K Q 821 (B,20,29) Transistor 2SA1036K Q 822 (B,17,33) Transistor DTC114EU Q 911 (A,6,100) Transistor 2SD2396 Q 912 (B,17,64) Transistor IMD2A Q 931 (B,70,86) Transistor IMX1 Q 991 (A,6,66) Transistor 2SD2396 Q 992 (B,25,50) Transistor IMD2A D 551 (A,66,104) Diode S5688G D 552 (A,63,104) Diode S5688G D 831 (A,139,18) Diode 1SS133 D 832 (A,122,23) Diode 1SS133 D 833 (A,114,24) Diode 1SS133 D 834 (A,111,19) Diode 1SS133 D 835 (A,113,10) Diode 1SS133 D 836 (A,126,25) Diode 1SS133 D 837 (A,134,21) Diode 1SS133 D 838 (A,119,18) Diode 1SS133 D 839 (A,117,18) Diode 1SS133 D 840 (A,118,15) Diode 1SS133 D 841 (A,116,15) Diode 1SS133 D 842 (A,130,25) Diode 1SS133 D 901 (A,69,113) Diode S5688G D 902 (A,72,110) Diode S5688G D 911 (A,30,78) Diode S5688G D 912 (A,18,60) Diode HZS6L(B2) D 931 (A,55,93) Diode HZS7L(C3) D 932 (A,60,91) Diode HZS7L(A1) D 991 (A,13,48) Diode HZS7L(C3) L 151 (A,141,79) Inductor LAU2R2K L 401 (A,155,55) Inductor LAU1R0K L 402 (A,155,92) Inductor LAU1R0K L 404 (A,155,99) Ferri-Inductor LAU4R7K L 601 (A,64,64) Ferri-Inductor LAU100K L 801 (A,28,15) Inductor LAU2R2K L 901 (A,35,103) Choke Coil 600µH CTH1280 X 601 (A,101,61) Radiator 12.58291MHz CSS1402 >FU352 (B,140,136) Fuse 3A CEK1286 AR401 (A,159,119) Surge Protector DSP-201M-S00B Z 401 (A,163,100) FM/AM Tuner Unit CWE1646 > Fuse 10A CEK1208 RESISTORS R 153 (B,127,104) RS1/16S471J R 154 (B,147,93) RS1/16S471J R 155 (B,127,102) RS1/16S471J R 156 (B,136,94) RS1/16S471J R 157 (B,84,79) RAB4C102J R 301 (A,100,96) RD1/4PU153J R 353 (B,141,122) RS1/16S471J R 354 (B,163,125) RS1/16S471J R 357 (B,145,130) RS1/16S223J R 358 (B,160,134) RS1/16S223J R 405 (B,158,62) RS1/16S681J R 407 (B,159,83) RS1/16S681J R 408 (B,159,85) RS1/16S681J R 409 (B,159,86) RS1/16S681J R 410 (B,159,88) RS1/16S681J R 414 (B,156,88) RS1/16S0R0J R 420 (B,105,44) RS1/16S681J R 421 (B,159,79) RS1/16S473J R 454 (B,133,114) RS1/16S103J R 455 (B,141,132) RS1/16S153J R 456 (B,139,132) RS1/16S221J R 457 (A,120,54) RD1/4PU681J R 601 (B,102,49) RS1/16S473J R 603 (B,63,75) RS1/16S103J R 604 (B,60,75) RS1/16S103J R 605 (B,84,21) RS1/16S0R0J R 606 (B,110,41) RS1/16S104J R 607 (A,110,51) RD1/4PU222J R 608 (B,104,63) RS1/16S0R0J R 609 (A,102,47) RD1/4PU473J Circuit Symbol and No. Part No. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-2700/XU/UC 35 5 6 7 8 5 6 7 8 C D F A B E R 610 (A,129,44) RD1/4PU681J R 611 (B,105,50) RS1/16S473J R 612 (B,111,14) RS1/16S104J R 613 (B,107,24) RS1/16S473J R 621 (A,18,131) RD1/4PU102J R 622 (A,21,131) RD1/4PU102J R 633 (B,65,40) RS1/16S104J R 721 (B,80,23) RS1/16S221J R 729 (B,54,57) RS1/16S0R0J R 730 (A,74,38) RD1/4PU102J R 731 (A,77,33) RD1/4PU102J R 732 (B,110,43) RS1/16S0R0J R 733 (A,80,33) RD1/4PU102J R 736 (A,98,34) RD1/4PU221J R 737 (B,56,24) RS1/16S221J R 738 (B,94,38) RS1/16S221J R 741 (B,50,17) RS1/16S221J R 751 (B,55,21) RS1/16S0R0J R 801 (B,24,27) RS1/16S153J R 802 (B,28,20) RS1/16S153J R 803 (B,13,36) RS1/16S222J R 821 (B,22,33) RS1/16S222J R 823 (B,26,31) RS1/16S103J R 833 (B,105,16) RS1/16S222J R 834 (B,88,15) RS1/16S222J R 836 (B,131,21) RS1/16S104J R 837 (A,128,21) RD1/4PU103J R 838 (A,113,44) RD1/4PU102J R 841 (B,15,28) RS1/16S1R0J R 848 (A,100,41) RD1/4PU102J R 851 (A,97,41) RD1/4PU102J R 852 (B,112,17) RS1/16S102J R 853 (B,107,22) RS1/16S102J R 854 (B,105,14) RS1/16S222J R 855 (B,103,20) RS1/16S222J R 857 (B,104,18) RS1/16S222J R 858 (A,127,27) RD1/4PU102J R 911 (B,11,68) RS1/16S223J R 912 (A,14,68) RD1/4PU152J R 923 (B,10,110) RS1/16S473J R 931 (B,62,92) RS1/16S473J R 932 (B,65,85) RS1/16S104J R 933 (A,54,99) RD1/4PU102J R 934 (B,64,95) RS1/16S473J R 935 (B,64,92) RS1/16S473J R 936 (B,70,89) RS1/16S473J R 940 (B,66,74) RS1/16S104J R 941 (B,66,72) RS1/16S104J R 955 (B,42,76) RS1/16S473J R 961 (B,59,68) RS1/16S102J R 962 (B,45,66) RS1/16S822J R 971 (B,85,88) RS1/16S0R0J R 981 (A,136,38) RD1/4PU1R8J R 991 (A,13,53) RD1/4PU271J R 992 (A,18,50) RD1/4PU121J R 993 (B,30,62) RS1/16S272J R 994 (B,30,56) RS1/16S472J CAPACITORS Circuit Symbol and No. Part No. C 151 (B,159,71) CKSRYB224K16 C 152 (B,159,73) CKSRYB224K16 C 153 (B,122,74) CKSRYB105K10 C 154 (B,145,82) CKSRYB105K10 C 155 (A,121,78) CEJQ4R7M35 C 156 (A,143,88) CEJQ4R7M35 C 157 (B,123,85) CKSRYB153K50 C 158 (B,143,95) CKSRYB153K50 C 161 (B,125,99) CCSRCH100D50 C 162 (B,139,94) CCSRCH100D50 C 163 (B,131,95) CCSRCH100D50 C 164 (B,139,96) CCSRCH100D50 C 165 (B,140,70) CKSRYB104K16 C 166 (A,135,66) CEJQ470M10 C 167 (A,124,66) CEJQ100M16 C 301 (A,135,111) CFTNA224J50 C 302 (A,145,119) CFTNA224J50 C 303 (A,130,111) CFTNA224J50 C 304 (A,143,125) CFTNA224J50 C 309 (B,135,136) CKSQYB225K10 C 310 (B,122,143) CKSQYB225K10 C 311 (A,99,104) CEJQ2R2M50 C 312 (A,100,118) CEJQ100M16 C 313 (B,40,122) CKSRYB104K16 C 353 (A,132,102) CEJQ2R2M50 C 354 (A,140,102) CEJQ2R2M50 C 401 (B,164,67) CKSRYB103K50 C 402 (B,153,56) CKSRYB103K50 C 403 (A,150,53) CEJQ470M6R3 C 404 (A,153,87) CEJQ101M10 C 405 (B,166,94) CKSRYB104K25 C 420 (B,112,68) CCSRCH470J50 C 451 (A,134,131) CEJQ330M10 C 551 (B,76,93) CKSQYB103K50 C 552 (B,70,99) CKSQYB103K50 C 601 (B,54,64) CKSRYB104K25 C 604 (B,97,64) CCSRCH200J50 C 605 (B,101,64) CCSRCH200J50 C 610 (A,94,71) CEJQ4R7M35 C 611 (B,97,68) CKSRYB224K16 C 728 (B,42,19) CKSRYB104K16 C 801 (B,11,36) CKSRYB104K16 C 901 (A,46,121) 3300µF/16V CCH1494 C 911 (A,16,76) CEJQ470M10 C 912 (B,12,64) CKSRYB103K50 C 913 (A,25,86) 470µF/16V CCH1331 C 921 (A,14,115) CEJQ101M16 C 922 (A,18,107) CEJQ221M10 C 923 (B,18,110) CKSRYB103K50 C 924 (B,17,101) CKSRYB103K50 C 961 (B,50,66) CKSRYB473K50 C 963 (A,46,69) CEJQ100M16 C 982 (B,145,40) CKSRYB103K50 C 983 (A,147,35) CEJQ220M16 C 991 (B,20,50) CKSRYB473K50 C 992 (A,26,60) CEJQ101M16 B Circuit Symbol and No. Part No. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-2700/XU/UC 36 1 2 3 4 1 2 3 4 C D F A B E Unit Number: Unit Name:Keyboard Unit MISCELLANEOUS IC 1801 (B,29,96) IC PD6340A D 1801 (B,19,40) Diode MA152WK D 1802 (B,24,40) Diode MA152WA D 1803 (A,25,38) LED CL-490S-WF-SD D 1804 (A,25,128) LED CL-490S-WF-SD D 1805 (A,13,22) LED SML-310PT D 1806 (A,26,9) LED SML-310PT D 1807 (A,30,27) LED SML-310PT D 1808 (A,39,50) LED SML-310PT D 1809 (A,5,10) LED SML-310PT D 1810 (A,34,9) LED SML-310PT D 1811 (A,39,84) LED SML-310PT D 1812 (A,39,73) LED SML-310PT D 1813 (A,39,61) LED SML-310PT D 1814 (A,39,96) LED SML-310PT D 1815 (A,39,107) LED SML-310PT D 1816 (A,39,119) LED SML-310PT D 1817 (A,39,35) LED SML-310PT D 1818 (A,39,131) LED SML-310PT X 1801 (B,37,83) Ceramic Resonator 5.00MHzCSS1547 S 1827 (A,23,19) Switch(VOLUME) YSD5002 IL 1801 (B,23,147) Lamp 40mA,14V CEL1651 LCD1801 (A,16,45) LCD YAW5021 RESISTORS R 1801 (B,23,43) RS1/16S222J R 1802 (B,20,43) RS1/16S222J R 1803 (B,22,33) RS1/16S151J R 1804 (B,22,31) RS1/16S181J R 1805 (B,19,34) RS1/16S181J R 1806 (B,29,142) RS1/16S181J R 1807 (B,26,142) RS1/16S181J R 1808 (B,13,31) RS1/16S181J R 1809 (B,24,33) RS1/16S151J R 1810 (B,25,30) RS1/16S181J R 1811 (B,21,35) RS1/16S181J R 1812 (B,29,140) RS1/16S181J R 1813 (B,26,140) RS1/16S181J R 1814 (B,15,31) RS1/16S181J R 1815 (B,25,33) RS1/16S151J R 1816 (B,25,29) RS1/16S151J R 1817 (B,22,35) RS1/16S151J R 1818 (B,29,137) RS1/16S151J R 1819 (B,26,137) RS1/16S151J R 1820 (B,17,31) RS1/16S151J R 1821 (B,27,25) RS1/16S151J R 1831 (B,33,23) RS1/16S472J R 1832 (B,35,23) RS1/16S472J R 1834 (B,14,21) RS1/16S473J CAPACITORS C 1802 (B,27,52) CKSRYF104Z25 C 1811 (A,25,32) CKSRYF104Z25 C 1812 (A,20,129) CKSRYF104Z25 Circuit Symbol and No. Part No. C Unit Number:CWX3110 Unit Name:CD Core Unit(S10) MISCELLANEOUS IC 201 (A,35,25) IC UPD63712AGC IC 301 (A,45,81) IC BA5835FP IC 701 (B,53,56) IC NJM2885DL1-33 Q 101 (B,22,12) Transistor 2SA1577 X 201 (A,45,36) Ceramic Resonator 16.934MHz CSS1603 S 901 (A,15,44) Switch(HOME) CSN1067 S 903 (B,53,101) Switch(DSCSNS) CSN1068 S 904 (B,35,109) Switch(12EJ) CSN1067 S 905 (B,48,110) Switch(8EJ) CSN1067 RESISTORS R 101 (B,26,13) RS1/10SR2R4J R 102 (B,28,15) RS1/10SR2R4J R 103 (B,29,12) RS1/10SR2R7J R 201 (A,58,26) RS1/16SS102J R 214 (A,23,28) RS1/16SS332J R 215 (A,21,27) RS1/16SS183J R 216 (A,24,19) RS1/16SS122J R 217 (A,22,15) RS1/16SS562J R 218 (A,24,16) RS1/16SS472J R 235 (A,27,44) RS1/16SS103J R 236 (A,31,46) RS1/16SS103J R 301 (A,54,73) RS1/16SS183J R 302 (A,54,70) RS1/16SS822J R 303 (A,45,70) RS1/16SS183J R 304 (A,47,69) RS1/16SS822J R 305 (A,34,75) RS1/16SS183J R 306 (A,32,69) RS1/16SS183J R 307 (A,38,74) RS1/16SS183J R 308 (A,36,67) RS1/16SS183J R 601 (B,52,43) RS1/16SS101J R 602 (B,46,42) RS1/16SS101J R 603 (B,48,48) RS1/16SS0R0J R 901 (B,48,103) RS1/16SS104J R 902 (B,46,105) RS1/16SS473J R 903 (B,44,106) RS1/16SS273J CAPACITORS C 103 (B,13,8) 100µF/16V CCH1504 C 109 (A,34,12) CKSSYB104K10 C 201 (A,45,19) CKSSYB104K10 C 202 (A,53,21) CKSSYB102K50 C 205 (B,37,36) 22µF/6.3V CCH1507 C 206 (B,40,30) CKSSYB103K16 C 207 (A,46,30) CKSSYB104K10 C 209 (A,46,31) CKSSYB104K10 C 210 (A,41,35) CKSSYB104K10 C 211 (A,33,35) CKSSYB104K10 C 213 (A,21,29) CKSSYB103K16 C 214 (A,23,26) CKSSYB104K10 C 215 (A,25,23) CKSSYB104K10 C 216 (A,24,21) CKSSYB103K16 C 217 (A,21,18) CCSSCH560J50 Circuit Symbol and No. Part No. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-2700/XU/UC 37 5 6 7 8 5 6 7 8 C D F A B E C 218 (A,24,14) CCSSCH5R0C50 C 219 (A,28,14) CKSSYB104K10 C 220 (B,27,24) CKSSYB104K10 C 221 (B,41,21) CKSSYB104K10 C 222 (A,35,12) CKSSYB103K16 C 223 (A,37,14) CCSSCH680J50 C 224 (A,45,11) CCSSCH470J50 C 225 (A,46,14) CKSSYB103K16 C 231 (A,30,43) CKSSYB102K50 C 232 (B,38,64) CKSSYB102K50 C 301 (B,37,74) 100µF/16V CCH1504 C 302 (A,54,71) CKSSYB221K50 C 303 (A,45,68) CKSSYB221K50 C 304 (A,33,73) CKSSYB472K25 C 305 (A,36,74) CKSSYB103K16 C 306 (B,45,94) CKSSYB104K10 C 501 (B,45,51) CKSSYB103K16 C 502 (A,61,68) CKSSYB103K16 C 703 (B,47,61) CKSQYB104K16 C 704 (B,54,63) CKSQYB105K10 Miscellaneous Parts List Pickup Unit(P10)(Service) CXX1647 M 1 Motor Unit(SPINDLE) CXC4440 M 2 Motor Unit(LOADING/CARRIAGE) CXB8933 Circuit Symbol and No. Part No. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-2700/XU/UC 38 1 2 3 4 1 2 3 4 C D F A B E 6. ADJUSTMENT 6.1 CD ADJUSTMENT 1) Cautions on adjustments • In this product the single voltage (3.3V) is used for the regulator. The reference voltage is the REFO1 (1.65V) instead of the GND. If you should mistakenly short the REFO1 with the GND during adjustment, accurate voltage will not be obtained, and the servo’s misoperation will apply excessive shock to the pickup. To avoid such problems: a. Do not mix up the REFO1 with the GND when connecting the (-) probe of measuring instruments. Especially on an oscilloscope, avoid connecting the (-) probe for CH1 to the GND. b. In many cases, measuring instruments have the same potential as that for the (-) probe. Be sure to set the measuring instruments to the floating state. c. If you have mistakenly connected the REFO1 to the GND, turn off the regulator or the power immediately. • Before mounting and removing filters or leads for adjustment, be sure to turn off the regulator. • For stable circuit operation, keep the mechanism operating for about one minute or more after the regulator is turned on. • In the test mode, any software protections will not work. Avoid applying any mechanical or electrical shock to the mechanism during adjustment. • The RFI and RFO signals with a wide frequency range are easy to oscillate. When observing the signals, insert a resistor of 1k ohms in series. • The load and eject operation is not guarantied with the mechanism upside down. If the mechanism is blocked due to mistaken eject operation, reset the product or turn off and on the ACC to restore it. 2) Test mode This mode is used to adjust the CD mechanism module. • To enter the test mode. While pressing the 4 and 6 keys at the same time, reset. • To exit from the test mode. Turn off the ACC and back up. Notes: a. During ejection, do not press any other keys than the EJECT key until the loaded disc is ejected. b. If you have pressed the (→) key or (←) key during focus search, turn off the power immediately to protect the actuator from damage caused by the lens stuck. c. For the TR jump modes except 100TR, the track jump operation will continue even if the key is released. d. For the CRG move and 100TR jump modes, the tracking loop will be closed at the same time when the key is released. e. When the power is turned off and on, the jump mode is reset to the single TR (91), the RF amp gain is set to 0dB, and the auto-adjustment values are reset to the default settings. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-2700/XU/UC 39 5 6 7 8 5 6 7 8 C D F A B E [BAND] [BAND] [BAND] [BAND] [BAND] Power On (T.Offset is adjusted) TRK00 MIN00 SEC00 [CD]or[SOURCE] Source On TRK MIN [4]+[6]+Reset Test Mode In [3] [1] [1] Power On (T.Offset is not adjusted) TRK99 MIN99 SEC99 [2] [2] [2] [2] Power Off TRK MIN SEC Power Off TRK MIN SEC Power Off TRK MIN SEC Power Off TRK MIN SEC Focus Close / S curve check TRK91 MIN91 SEC91 [6] [1] [3] [6] [3] Focus Mode switching *2 TRK0xMIN0xSEC0x Tracking Servo Close TRK00 MIN00 SEC00 or TRK99 MIN99 SEC99 CRG- *8 TRK00 MIN00 SEC00 or TRK99 MIN99 SEC99 [→] [←] [→] [←] [→] [←] CRG+ *8 TRK00 MIN00 SEC00 or TRK99 MIN99 SEC99 Automatic adjustment display switching *3 TRK?? MIN?? SEC?? T.Close and F,T AGC and RF AGC Applicable servomechanism TRKxx MINxx SECxx [6] [3] T.Close and Applicable servomechanism TRKxx MINxx SECxx RF AGC / RF AGC coefficient display TRK?? MIN?? SEC?? CRG+ TRK8x MIN8x SEC8x or TRK9xMIN9xSEC9x CRG- TRK8x MIN8x SEC8x or TRK9xMIN9xSEC9x T.Balance adjustment T.Balance coefficient display TRK?? MIN?? SEC?? F,T,RF AGC / F.Bias display switching *7 TRK?? MIN?? SEC?? F,T AGC /F.Bias RF AGC TRKxx MINxx SECxx CRG/TR Jump value *5 switching TRKxx MINxx SECxx CRG/TR Jump + *4 TRKxx MINxx SECxx CRG/TR Jump - *4 *6 TRK xx MINxx SEC xx Tracking Open TRK8xMIN8xSEC8x or TRK9xMIN9xSEC9x Tracking Open TRK8x MIN8x SEC8x or TRK9xMIN9xSEC9x [Key] [BAND] [→] [6] [1] [2] [3] - - Power On / Off CRG + / TR Jump + (Direction of the external surface) CRG - / TR Jump - (Direction of the internal surface) CLS and AGC and Applicable servomechanism / AGC, AGC display switching RF Gain switching / Offset adjustment display / T.Balance adjustment / T.Open Close, S.Curve / SPDL 1X / 2X switching (Double-speed compatibility only) Gop measurement Forcus Mode switching / Tracking Close / CRG, TR Jump switching Test Mode Operation [KEY] Contents Display Rough Servo and RF AGC / F, T, RF AGC *1) TYP → -12dB TRK MIN SEC TRK 12 MIN 12 SEC 12 *2) Focus Close → S.Curve → F EQ measurement setting TRK 00 MIN 00 SEC 00 TRK 01 MIN 01 SEC 01 TRK 02 MIN 02 SEC 02 (TRK 99 MIN 99 SEC 99) *3) F.Offset Display → RF.Offset Display → T.Offset Display *4) 1TR/32TR/100TR *5) Single TR → 32TR → 100TR → CRG Move 9x(8x) : 91(81) 92(82) 93(83) 94(84) *6) Only at the time of CRG Move or 100TR Jump *7) TRK/MIN/SEC → F.AGC → T.AGC Gain → F.bias → RF AGC *8) CRG motor voltage = 2[V] [←] - Flow Chart www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-2700/XU/UC 40 1 2 3 4 1 2 3 4 C D F A B E 6.2 CHECKING THE GRATING AFTER CHANGING THE PICKUP UNIT • Note : The grating angle of the PU unit cannot be adjusted after the PU unit is changed. The PU unit in the CD mechanism module is adjusted on the production line to match the CD mechanism module and is thus the best adjusted PU unit for the CD mechanism module. Changing the PU unit is thus best considered as a last resort. However, if the PU unit must be changed, the grating should be checked using the procedure below. • Purpose : To check that the grating is within an acceptable range when the PU unit is changed. • Symptoms of Mal-adjustment : If the grating is off by a large amount symptoms such as being unable to close tracking, being unable to perform track search operations, or taking a long time for track searching. • Method : • Measuring Equipment • Measuring Points • Oscilloscope, Two L.P.F. • E, F, REFO1 • Disc • TCD-782 • Mode • TEST MODE • Checking Procedure 1. In test mode, load the disc and switch the 3V regulator on. 2. Using the → and ← buttons, move the PU unit to the innermost track. 3. Press key 3 to close focus, the display should read "91". Press key 2 to implement the tracking balance adjustment the display should now read "81". Press key 3. The display will change, returning to "81" on the fourth press. 4. As shown in the diagram above, monitor the LPF outputs using the oscilloscope and check that the phase difference is within 75° . Refer to the photographs supplied to determine the phase angle. 5. If the phase difference is determined to be greater than 75° try changing the PU unit to see if there is any improvement. If, after trying this a number of times, the grating angle does not become less than 75° then the mechanism should be judged to be at fault. • Note Because of eccentricity in the disc and a slight misalignment of the clamping center the grating waveform may be seen to "wobble" ( the phase difference changes as the disc rotates). The angle specified above indicates the average angle. • Hint Reloading the disc changes the clamp position and may decrease the "wobble". 100kΩ 390pF 100kΩ 390pF E VREF F VREF Xch Ych L.P.F. L.P.F. REFO1 F E CD CORE UNIT(S10) Oscilloscope www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-2700/XU/UC 41 5 6 7 8 5 6 7 8 C D F A B E Grating waveform 45° 0° 75° 60° 30° 90° Ech → Xch 20mV/div, AC Fch → Ych 20mV/div, AC www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-2700/XU/UC 42 1 2 3 4 1 2 3 4 C D F A B E 6.3 ERROR MODE - Error Messages If a CD is not operative or stopped during operation due to an error, the error mode is turned on and cause(s) of the error is indicated with a corresponding number. This arrangement is intended at reducing nonsense calls from the users and also for facilitating trouble analysis and repair work in servicing. (1) Basic Indication Method 1) When SERRORM is selected for the CSMOD (CD mode area for the system), error codes are written to DMIN (minutes display area) and DSEC (seconds display area). The same data is written to DMIN and DSEC. DTNO remains in blank as before. 2) Head unit display examples Depending on display capability of LCD used, display will vary as shown below. xx contains the error number. 8-digit display 6-digit display 4-digit display ERROR–xx ERR–xx E–xx (2) Error Code List Code Class Displayed error code Description of the code and potential cause(s) 10 Electricity Carriage Home NG CRG can't be moved to inner diameter. SERVO LSI Com- CRG can't be moved from inner diameter. munication Error → Failure on home switch or CRG move mechanism. Communication error between microcomputer and SERVO LSI. 11 Electricity Focus Servo NG Focusing not available. → Stains on rear side of disc or excessive vibrations on REWRITABLE. 12 Electricity Spindle Lock NG Spindle not locked. Sub-code is strange (not readable). Subcode NG → Failure on spindle, stains or damages on disc, or excessive vibrations. A disc not containing CD-R data is found. Turned over disc are found, though rarely. CD signal error. 17 Electricity Setup NG AGC protection doesn't work. Focus can be easily lost. → Damages or stains on disc, or excessive vibrations on REWRITABLE. 30 Electricity Search Time Out Failed to reach target address. → CRG tracking error or damages on disc. 44 Electricity ALL Skip Skip setting for all track. (CD-R/RW) 50 Mechanism CD On Mech Error Mechanical error during CD ON. → Defective loading motor, mechanical lock and mechanical sensor. A0 System Power Supply NG Power (VD) is ground faulted. → Failure on SW transistor or power supply (failure on connector). Remarks: Mechanical errors are not displayed (because a CD is turned off in these errors). Unreadable TOC does not constitute an error. An intended operation continues in this case. Upper digits of an error code are subdivided as shown below: 1x: Setup relevant errors, 3x: Search relevant errors, Ax: Other errors. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-2700/XU/UC 43 5 6 7 8 5 6 7 8 C D F A B E 6.4 SYSTEM MICROCOMPUTER TEST PROGRAM - PCL Output In the normal operation mode (with the detachable panel installed, the ACC switched ON, the standby mode cancelled), shift the TESTIN (Pin 15) terminal to H. The clock signal is output from the PCL terminal (Pin 14). The frequency of the clock signal is 786.432kHz that is one 16th of the fundamental frequency. The clock signal should be 786.432kHz ± 31.5Hz. If the clock signal is out of the range, the X'tal (X601) should be replaced with new one. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-2700/XU/UC 44 1 2 3 4 1 2 3 4 C D F A B E 7. GENERAL INFORMATION 7.1 DIAGNOSIS 7.1.1 DISASSEMBLY - Removing the CD Mechanism Module (Fig.1) 1 Fig.1 - Removing the Case (not shown) Grille Assy - Removing the Grille Assy (Fig.1) 1. Remove the Case. CD Mechanism Module 1 1 1 1 Fig.2 Tuner Amp Unit - Removing the Tuner Amp Unit (Fig.2) Remove the screw. 1 Remove the four screws. Disconnect the connector and then remove the CD Mechanism Module. 2 Release the two latchs and then remove the Grille Assy. 2 2 1 2 2 2 3 3 3 Remove the three screws. 2 Straighten the tabs at three locations indicated and then remove the Tuner Amp Unit. 3 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-2700/XU/UC 45 5 6 7 8 5 6 7 8 C D F A B E - How to hold the Mechanism Unit 1. Hold the top and bottom frame. 2. Do not squeeze top frame's front portion too tight, because it is fragile. - Removing the Upper and Lower Frames 1. With a disc clamped, remove the four springs (A), the two springs (B), the two springs (C), and the four screws. 2. To remove the upper frame, open it on the fulcrum A. 3. While lifting the carriage mechanism, remove the three dampers. 4. With the frames removed, insert the connectors coming from the main unit and eject the disc. Caution: Before installing the carriage mechanism in the frames, be sure to apply some alcohol to the dampers and set the mechanism to the clamp mode. Do not squeeze. Lower Frame Damper Carriage Mechanism A C A B B Damper Damper C A A A Upper Frame www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-2700/XU/UC 46 1 2 3 4 1 2 3 4 C D F A B E - Removing the Pickup Unit 1. Apply shorting solder to the Pickup flexible cable. Disconnect the cable. 2. Set the mechanism to the clamp mode. 3. Remove the lead wires from the inner holder. 4. Remove the washer, styling holder, change arm, and pickup lock arm. 5. While releasing from the hook of the inner holder, lift the end of the feed screw. Caution: In assembling, move the planet gear to the load/eject position before setting the feed screw in the inner holder. Shorting Solder Planet Gear Change Arm Inner Holder Styling Holder Feed Screw Washer Pickup Lock Arm www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-2700/XU/UC 47 5 6 7 8 5 6 7 8 C D F A B E 7.1.2 CONNECTOR FUNCTION DESCRIPTION Pin No. 1 2 3 4 5 6 7 8 B.UP GND ACC NC NC B.REM NC NC Pin No. 9 10 11 12 13 14 15 16 RL- FL- RL+ FL+ RR- FR- RR+ FR+ ANTENNA JACK REAR OUTPUT WIRED REMOTE CONTROL 10A 16 2 1 15 14 13 12 11 10 9 8 7 6 5 4 3 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-2700/XU/UC 48 1 2 3 4 1 2 3 4 C D F A B E 7.2 PARTS 7.2.1 IC Pin No. 1 2, 3 4 5, 6 7 8 9 10 11 12 13 14 15 16 17 18 19, 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35, 36 37 38 39 40 41 42 43 44, 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60 61 62 Function and Operation Model select input Not used GND Not used VDD Display microcomputer data input Display microcomputer communication data output A/D converter power supply output PLL data input PLL data output PLL clock output Clock adjustment output Test program input CD LSI serial data input CD LSI serial data output CD LSI serial clock output Not used Display microcomputer chip select output Illumination power output Not used CD LSI reset control output CD LSI command data control output CD LSI strobe output CD LSI ceramic oscillator oscillation output Driver output Load/eject output Driver control output Not used Output for dark current reduction circuit GND TEL mute input Rotary volume input 0, 1 ROM collection data output ROM collection clock output ROM collection chip select output RDS decoder receiving output (Not used) VD output Not used System power output Not used Wired remote control input Illumination input System mute output Auto antenna control output Not used E.VOL strobe output E.VOL data output E.VOL clock output Not used PLL chip enable output 2 PLL chip enable output RDS LK input (Not used) RDS clock input (Not used) RDS 57K input (Not used) Reset PLL lock detection input RDS clock input Pin Name MODEL1 NC AVSS NC AVREF1 KYDT DPDT ADPW TUNPDI TUNPDO TUNPCK PCL TESTIN XSI XSO XSCK NC swvdd ILMPW NC XRST XA0 XSTB XTALEN CONT LOEJ CLCONT NC DALMON VSS TELIN ROT0, 1 ROMDATA ROMCLK ROMCS RECEIVE VDCONT NC SYSPW NC STRKEY2 isens MUTE ANTPW NC VST VDT VCK NC TUNPCE2 TUNPCE RDT RDSLK RDS57K RESET LDET RCK I/O I I O O I O O O I I O O O O O O O O O O O O I I O O O O O I I O O O O O O O I I - Pin Functions(PE5462A) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-2700/XU/UC 49 5 6 7 8 5 6 7 8 C D F A B E 20 21 40 41 60 61 80 1 * PE5462A Pin No. 63 64 65 66 67 68 69, 70 71 72 73 74 75 76 77 78 79 80 Pin Name asens bsens dsens source VSS VDD X2, 1 IC(VPP) NC VSS AVDD AVREF1 SL TEMP VDSENS DISCSENS STRKEY1 I/O I I I I I I I I I Function and Operation ACC sense input Back up sense input Grille detach sense input Source sense input GND VDD Crystal oscillator connection pin GND Not used VSS VDD VDD Signal level input Temperature detection input VD power supply short circuit input DISC loading detection input Wired remote control input IC's marked by * are MOS type. Be careful in handling them because they are very liable to be damaged by electrostatic induction. BA33BC0FP - + Vref 3 2 1 VCC NC OUT Vref OCP TSD www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-2700/XU/UC 50 1 2 3 4 1 2 3 4 C D F A B E - Pin Functions(PD6340A) Pin No. Pin Name I/O Function and Operation 1-5 SEG4-0 O LCD segment output 6-9 COM3-0 O LCD common output 10 VLCD LCD drive power supply 11-14 KST3-0 O Key strobe output 15,16 KDT0,1 I Key data input (analogue input) 17 REW I Remote control reception input 18 DPDT I Display data input 19 NC Not used 20 KYDT O Key data output 21 MODA GND 22 X0 Crystal oscillator connection pin 23 X1 Crystal oscillator connection pin 24 VSS GND 25,26 KDT2,3 I Key data input 27 NC Not used 28 KST4 O Key strobe output 29-32 NC Not used 33-55 SEG35-13 O LCD segment output 56 VDD Power supply 57-64 SEG12-5 O LCD segment output * PD6340A NJM2388F84 NJM2885DL1-33 49 48 33 32 17 16 1 64 1 2 3 VDD GND 5 4 VOUT N.C. N.C. Vref IN 1 GND 2 OUT 3 Bandgap Reference Thermal Protection +- www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-2700/XU/UC 51 5 6 7 8 5 6 7 8 C D F A B E No. Symbol I/O Explain 1 AMANT I AM antenna input AM antenna input high impedance AMANT pin is connected with an all antenna by way of 4.7µH. (LAU type inductor) A series circuit including an inductor and a resistor is connected with RF ground for the countermeasure against the hum of power transmission line. 2 RFGND RF ground Ground of antenna block 3 FMANT I FM antenna input Input of FM antenna 75Ω Surge absorber(DSP-201M-S00B) is necessary. 4 VCC power supply The power supply for analog block. D.C 8.4V ± 0.3V 5 SL O signal level Output of FM/AM signals level 6 CE2 I chip enable-2 Chip enable for EEPROM ”Low” active 7 WC I write control You can write EEPROM, when EEPROM write control is “Low”. Ordinary non connection 8 CE1 I chip enable-1 Chip enable for AF•RF ”High” active 9 CK I clock Clock 10 DI I data in Data input 11 NC non connection Not used 12 OSCGND osc ground Ground of oscillator block 13 ROM_VDD power supply Power supply for EEPROM pin 13 is connected with a power supply of micro computer. 14 DO O data out Data output 15 DGND digital ground Ground of digital block 16 NC non connection Not used 17 VDD_3.3 power supply The power supply for digital block. 3.3V ± 0.2V 18 NC non connection Not used 19 NC non connection Not used 20 NC non connection Not used 21 NC non connection Not used 22 AUDIOGND audio ground Ground of audio block 23 L ch O L channel output FM stereo “L-ch” signal output or AM audio output 24 R ch O R channel output FM stereo “R-ch” signal output or AM audio output FMRF ANT adj RF adj FM ANT T51 CF52 CF51 RFGND OSCGND DGND AUDIOGND NC VCC VDD_3.3 3.3V 2.5V IC 4 3.3V 2.5V ← IC 2 2.5V WC CE2 ROM_VDD SL DI CK CE1 NC DO NC NC NC NC 7 6 13 5 10 9 8 11 14 18 19 20 21 1 3 2 12 15 22 16 4 17 IC 1 3.3V AM ANT FMRF ATT LPF OSC IC 3 EEPROM 5.0V IC 5 5V 3.3V ← ATT MIXER, IF AMP DET, FM MPX 24 23 Rch Lch - FM/AM Tuner Unit www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-2700/XU/UC 52 1 2 3 4 1 2 3 4 C D F A B E 7.2.2 DISPLAY - LCD(YAW5021) SEGMENT COMMON www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-2700/XU/UC 53 5 6 7 8 5 6 7 8 C D F A B E 7.3 OPERATIONAL FLOW CHART AVREF1, VDD, AVDD=5V Pin 7, 68, 74, 75 Power ON bsens=L asens=L bsens Pin 64 asens Pin 63 swvdd←L Pin 21 Source keys operative Completes power-on operation.(After that, proceed to each source operation.) SYSPW←H Pin 43 Starts communication with Grille microcomputer. Source ON 300ms 300ms In case of the above signal, the communication with Grille microcomputer may fail. If the time interval is not 300msec, the oscillator may be defective. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-2700/XU/UC 54 1 2 3 4 1 2 3 4 C D F A B E 7.4 CLEANING Before shipping out the product, be sure to clean the following portions by using the prescribed cleaning tools: Portions to be cleaned Cleaning tools CD pickup lenses Cleaning liquid : GEM1004 Cleaning paper : GED-008 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-2700/XU/UC 55 5 6 7 8 5 6 7 8 C D F A B E 8. OPERATIONS www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-2700/XU/UC 56 1 2 3 4 1 2 3 4 C D F A B E About the fixing screws for the front panel If you do not operate the Detaching and Replacing the Front Panel Function, use the supplied fixing screws and fix the front panel to this unit. Fixing screw (CBA1488) Fixing screw (CBA1488) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-2700/XU/UC 57 5 6 7 8 5 6 7 8 C D F A B E + ≠ + ≠ + ≠ + ≠ + ≠ + ≠ This Product Blue/white To system control terminal of the power amp or Auto-antenna relay control terminal (max. 300 mA 12 V DC). Connecting cords with RCA pin plugs (sold separately) System remote control Rear speaker Rear speaker Right Front speaker Rear speaker White Gray White/black Green Green/black Gray/black Violet Violet/black Front speaker Rear speaker Left Perform these connections when using the optional amplifier. With a 2 speaker system, do not connect anything to the speaker leads that are not connected to speakers. Yellow To terminal always supplied with power regardless of ignition switch position. Black (ground) To vehicle (metal) body. Red To electric terminal controlled by ignition switch (12 V DC) ON/OFF. Power amp (sold separately) Antenna jack Rear output Jack for the Wired Remote Control Please see the Instruction Manual for the Wired Remote Control (sold separately). Fuse - Connection Diagram www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com DEH-2700/XU/UC 58 1 2 3 4 1 2 3 4 C D F A B E - Jigs List Test Disc L.P.F. TCD-782 Checking the grating g g g Checking the grating g g g (Two pieces) ( ) Name Jig No. Remarks www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com
