ORDER NO. PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A. PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936 PIONEER CORPORATION 2005 6 0 7 DVD/CD FM/AM - + STANDBY/ON VOLUME OPEN/CLOSE XV-DV232 RRV3115 DVD/CD RECEIVER XV-DV232 (DCS-232) XV-DV240 XV-DV535W THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S). DCS-232 is combination of the following components. Model Type Power Requirement Regional restriction codes (Region No.) Remarks XV-DV232 WYXJ AC220-240V 2 XV-DV232 WVXJ AC220-240V 2 XV-DV240 WYXJ AC220-240V 2 XV-DV240 WVXJ AC220-240V 2 XV-DV535W WYXJ AC220-240V 2 XV-DV535W WVXJ AC220-240V 2 Component System Service Manual Remarks 5.1CH SURROUND SYSTEM DCS-232 RRV3114 DVD/CD RECEIVER XV-DV232 RRV3115 This manual SPEAKER SYSTEM S-DV232 RRV3070 For details, refer to "Important Check Points for Good Servicing". T-ZZK APR. 2005 printed in Japan www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com XV-DV232 2 1 2 3 4 1 2 3 4 C D F A B E SAFETY INFORMATION This service manual is intended for qualified service technicians ; it is not meant for the casual do- it-yourselfer. Qualified technicians have the necessary test equipment and tools, and have been trained to properly and safely repair complex products such as those covered by this manual.Improperly performed repairs can adversely affect the safety and reliability of the product and may void the warranty. If you are not qualified to perform the repair of this product properly and safely, you should not risk trying to do so and refer the repair to a qualified service technician. WARNING ! THE AEL (ACCESSIBLE EMISSION LEVEL) OF THE LASER POWER OUTPUT IS LESS THAN CLASS 1 BUT THE LASER COMPONENT IS CAPABLE OF EMITTING RADIATION EXCEEDING THE LIMIT FOR CLASS 1. A SPECIALLY INSTRUCTED PERSON SHOULD DO SERVICING OPERATION OF THE APPARATUS. LASER DIODE CHARACTERISTICS FOR DVD : MAXIMUM OUTPUT POWER : 5 mW WAVELENGTH : 650 nm FOR CD : MAXIMUM OUTPUT POWER : 7 mW WAVELENGTH : 780 nm Additional Laser Caution 1. Laser Interlock Mechanism • Loading switch (S101 on the LOAB Assy) is used for interlock mechanism of the laser. When this switch turned ON in SW2 (CLOSE) side (OPEN signal is 0V and CLOSE signal is 3.5V), a laser becomes the status which can completely oscillation. Furthermore, the laser completely oscillates in the disc judgment and disc playback. When player is power ON state and laser diode is not completely oscillating, 780nm laser diode is always oscillating by half power. • Laser diode is driving with Q307 (650nm LD) and Q308 (780nm LD) on the DVD MAIN Assy. Therefore, when short-circuit between the emitter and collector of these transistors or the base voltage is supplied for transistors turn on, the laser oscillates. (failure mode) • In the test mode ∗ , there is the mode that the laser oscillates except for the disc judgment and playback. LD ON mode in the test mode oscillates with the laser forcibly. The interlock mechanism mentioned above becomes invalid in this mode. 2. When the cover is open, close viewing through the objective lens with the naked eye will cause exposure to the laser beam. LABEL CHECK VRW1872 Name Label ∗ : Refer to page 57. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com XV-DV232 3 5 6 7 8 5 6 7 8 C D F A B E [Important Check Points for Good Servicing] In this manual, procedures that must be performed during repairs are marked with the below symbol. Please be sure to confirm and follow these procedures. 1. Product safety Please conform to product regulations (such as safety and radiation regulations), and maintain a safe servicing environment by following the safety instructions described in this manual. 1 Use specified parts for repair. Use genuine parts. Be sure to use important parts for safety. 2 Do not perform modifications without proper instructions. Please follow the specified safety methods when modification(addition/change of parts) is required due to interferences such as radio/TV interference and foreign noise. 3 Make sure the soldering of repaired locations is properly performed. When you solder while repairing, please be sure that there are no cold solder and other debris. Soldering should be finished with the proper quantity. (Refer to the example) 4 Make sure the screws are tightly fastened. Please be sure that all screws are fastened, and that there are no loose screws. 5 Make sure each connectors are correctly inserted. Please be sure that all connectors are inserted, and that there are no imperfect insertion. 6 Make sure the wiring cables are set to their original state. Please replace the wiring and cables to the original state after repairs. In addition, be sure that there are no pinched wires, etc. 7 Make sure screws and soldering scraps do not remain inside the product. Please check that neither solder debris nor screws remain inside the product. 8 There should be no semi-broken wires, scratches, melting, etc. on the coating of the power cord. Damaged power cords may lead to fire accidents, so please be sure that there are no damages. If you find a damaged power cord, please exchange it with a suitable one. 9 There should be no spark traces or similar marks on the power plug. When spark traces or similar marks are found on the power supply plug, please check the connection and advise on secure connections and suitable usage. Please exchange the power cord if necessary. 0 Safe environment should be secured during servicing. When you perform repairs, please pay attention to static electricity, furniture, household articles, etc. in order to prevent injuries. Please pay attention to your surroundings and repair safely. 2. Adjustments To keep the original performance of the products, optimum adjustments and confirmation of characteristics within specification. Adjustments should be performed in accordance with the procedures/instructions described in this manual. 4. Cleaning For parts that require cleaning, such as optical pickups, tape deck heads, lenses and mirrors used in projection monitors, proper cleaning should be performed to restore their performances. 3. Lubricants, Glues, and Replacement parts Use grease and adhesives that are equal to the specified substance. Make sure the proper amount is applied. 5. Shipping mode and Shipping screws To protect products from damages or failures during transit, the shipping mode should be set or the shipping screws should be installed before shipment. Please be sure to follow this method especially if it is specified in this manual. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com XV-DV232 4 1 2 3 4 1 2 3 4 C D F A B E CONTENTS SAFETY INFORMATION..................................................................................................................................... 2 1. SPECIFICATIONS ............................................................................................................................................ 5 2. EXPLODED VIEWS AND PARTS LIST ............................................................................................................ 6 2.1 PACKING ................................................................................................................................................... 6 2.2 EXTERIOR SECTION................................................................................................................................ 8 2.3 05 LOADER ASSY................................................................................................................................... 10 2.4 TM ASSY VK1AVC................................................................................................................................... 12 3. BLOCK DIAGRAM AND SCHEMATIC DIAGRAM.......................................................................................... 14 3.1 BLOCK DIAGRAM ................................................................................................................................... 14 3.2 LOAB ASSY and OVERALL WIRING CONNECTION DIAGRAM ........................................................... 16 3.3 DVD MAIN ASSY (1/4)............................................................................................................................. 18 3.4 DVD MAIN ASSY (2/4)............................................................................................................................. 20 3.5 DVD MAIN ASSY (3/4)............................................................................................................................. 22 3.6 DVD MAIN ASSY (4/4)............................................................................................................................. 24 3.7 DAMP ASSY (1/2).................................................................................................................................... 26 3.8 DAMP ASSY (2/2).................................................................................................................................... 28 3.9 FUNCTION ASSY.................................................................................................................................... 30 3.10 POWER SUPPLY UNIT.......................................................................................................................... 32 3.11 WAVEFORMS ........................................................................................................................................ 34 4. PCB CONNECTION DIAGRAM ..................................................................................................................... 37 4.1 LOAB ASSY............................................................................................................................................. 37 4.2 DVD MAIN ASSY ..................................................................................................................................... 38 4.3 DAMP ASSY ............................................................................................................................................ 42 4.4 FUNCTION ASSY.................................................................................................................................... 44 4.5 POWER SUPPLY UNIT............................................................................................................................ 46 5. PCB PARTS LIST ........................................................................................................................................... 48 6. ADJUSTMENT ............................................................................................................................................... 52 6.1 ADJUSTMENT ITEMS AND LOCATION ................................................................................................. 52 6.2 JIGS AND MEASURING INSTRUMENTS............................................................................................... 52 6.3 NECESSARY ADJUSTMENT POINTS ................................................................................................... 53 6.4 TEST MODE ............................................................................................................................................ 54 6.5 MECHANISM ADJUSTMENT.................................................................................................................. 55 7. GENERAL INFORMATION............................................................................................................................. 57 7.1 DIAGNOSIS ............................................................................................................................................. 57 7.1.1 TEST MODE...................................................................................................................................... 57 7.1.2 DISPLAY SPECIFICATION OF THE TEST MODE............................................................................ 58 7.1.3 FUNCTIONAL SPECIFICATION OF THE SHORTCUT KEY ............................................................ 59 7.1.4 SPECIFICATION OF MODEL INFORMATION DISPLAY .................................................................. 60 7.1.5 FUNCTIONAL SPECIFICATION OF THE SERVICE MODE ............................................................. 61 7.1.6 SERVICE TEST MODE ..................................................................................................................... 62 7.1.7 METHOD FOR DIAGNOSING DEGRADATION OF THE LDS ON THE PICKUP ASSY .................. 65 7.1.8 DVD TROUBLE SHOOTING.............................................................................................................. 66 7.1.9 ID NUMBER AND ID DATA SETTING ............................................................................................... 69 7.1.10 POWER ON SEQUENCE................................................................................................................ 72 7.1.11 CIRCUIT DESCRIPTION OF DIGITAL AMP. SECTION.................................................................. 73 7.1.12 DISASSEMBLY................................................................................................................................ 74 7.2 PARTS...................................................................................................................................................... 81 7.2.1 IC ....................................................................................................................................................... 81 8. PANEL FACILITIES ...................................................................................................................................... 104 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com XV-DV232 5 5 6 7 8 5 6 7 8 C D F A B E 1. SPECIFICATIONS • Amplifier section Continuous Power Output (RMS): Front, Center, Surround . . . .60 W per channel (1 kHz, 10 % T.H.D., 4 Ω) 50 W per channel (1 kHz, 10 % T.H.D., 6 Ω) Subwoofer 60 W (100 Hz, 10 % T.H.D., 4 Ω) 50 W (100 Hz, 10 % T.H.D., 6 Ω) • Disc section Digital audio characteristics . . . . . . . . . DVD fs: 96 kHz, 24-bit Type. . . . . . . DVD system, video CD system and compact disc digital audio system Frequency response . . . 4 Hz to 44 kHz (96kHz sampling) / 4 Hz to 22 kHz (48kHz sampling) Wow and Flutter. . . . . . . . .Limit of measurement (±0.001 % W.PEAK) or less (JEITA) • FM tuner section Frequency range . . . . . . . . . . . . 87.5 - 108 MHz Antenna . . . . . . . . . . . . . . . . . 75 Ω, unbalanced • AM tuner section Frequency range . . . . . . . 531 kHz to 1,602 kHz Antenna . . . . . . . . . . . . . . . . . . . . Loop antenna • Miscellaneous Power requirements . . . AC 220-240 V, 50/60 Hz Power consumption . . . . . . . . . . . . . . . . . . 45 W Power consumption in standby. . . . . . . . . 0.4 W Dimensions . . . . . . 420 (W) 60 (H) 331.5(D) mm Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.1 kg • Accessories (DVD/CD receiver) Remote control . . . . . . . . . . . . . . . . . . . . . . . . . 1 AA/R6 dry cell batteries . . . . . . . . . . . . . . . . . . 2 Video cable (yellow plugs) . . . . . . . . . . . . . . . . 1 AM loop antenna. . . . . . . . . . . . . . . . . . . . . . . . 1 FM antenna . . . . . . . . . . . . . . . . . . . . . . . . . . . .1 Power cord. . . . . . . . . . . . . . . . . . . . . . . . . . . . .1 Setup Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 Warranty card . . . . . . . . . . . . . . . . . . . . . . . . . .1 Operating instructions Accessories • Power cord (WYXJ: ADG1154) • FM Antenna (ADH7030) • AM Loop Antenna (ATB7013) • Video Cable (L = 1.5m) (XDE3046) • Remote Control (AXD7407) • Dry Cell Batteries Yellow Note • Specifications and design subject to possible modification without notice, due to improvements. Manufactured under license from Dolby Laboratories.“Dolby”, “Pro Logic”, and the double-D symbol are trademarks of Dolby Laboratories. “DTS” and “DTS Digital Surround” are registered trademarks of Digital Theater Systems, Inc. AUDIO SUBTITLE ANGLE ZOOM STANDBY/ON MUTE DVD/CD FM/AM TUNER LINE SYSTEM SETUP HOME MENU DVD MENU TOP MENU RETURN TEST TONE SOUND MODE SHIFT CLEAR SLEEP DISPLAY VOLUME 1 2 3 4 5 6 7 8 9 0 TUNE TUNE ST ST ENTER FRONT SURROUND Super Video CD (Super VCD) Disc/content format playback compatibility This player is compatible with a wide range of disc types (media) and formats. Playable discs will generally feature one of the following logos on the disc and/or disc packaging. Note however that some disc types, such as recordable CD and DVD, may be in an unplayable format. See the Disc compatibility tablebelow for more information. • is a trademark of Fuji Photo Film Co. Ltd. • is a trademark of DVD Format/Logo Licensing Corporation • Also compatible with KODAK Picture CD This player supports the IECís Super VCD stan- dard for superior picture quality, dual soundtracks, and widescreen support. DVD-Video DVD-R DVD-RW Video CD Fujicolor CD Audio CD CD-R CD-RW VIDEO CD • Power cord (WVXJ : ADG1156) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com XV-DV232 6 1 2 3 4 1 2 3 4 C D F A B E 2. EXPLODED VIEWS AND PARTS LIST 2.1 PACKING Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List. The mark found on some component parts indicates the importance of the safety factor of the part. Therefore, when replacing, be sure to use parts of identical designation. Screws adjacent to mark on product are used for disassembly. For the applying amount of lubricants or glue, follow the instructions in this manual. (In the case of no amount instructions, apply as you think it appropriate.) NOTES: Front side Front side For XV-DV535W and XV-DV240 Speaker system S-DV232 For WYXJ type For WVXJ type For DCS-232 (XV-DV232) For WYXJ type For WVXJ type 15 5 21 19 20 16 18 18 4 7 8 to 14 1 1 6 2 21 19 22 23 20 18 15 16 5 18 18 4 8,9,11,12,13 6 2 1 1 7 10,14 (WVXJ) (WYXJ) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com XV-DV232 7 5 6 7 8 5 6 7 8 C D F A B E (1) PACKING SECTION PARTS LIST (2) CONTRAST TABLE XV-DV535W/WYXJ, WVXJ, XV-DV240/WYXJ, WVXJ, XV-DV232/WYXJ and WVXJ are constructed the same except for the following : Mark No. Description Part No. > 1 Power Cord See Contrast table(2) 2 FM Antenna ADH7030 3 • • • • • • 4 AM Loop Antenna ATB7013 NSP 5 Dry Cell Batteries(R6/AA) VEM1031 6 Video Cable XDE3046 NSP 7 Warranty Card ARY7065 8 Operating Instructions See Contrast table(2) (Dutch/Italian/Spanish) 9 Operating Instructions See Contrast table(2) (English/French/German) 10 Operating Instructions See Contrast table(2) (English) 11 Setup Guide See Contrast table(2) (German/Italian) 12 Setup Guide See Contrast table(2) (Dutch/Spanish) 13 Setup Guide See Contrast table(2) (English/French) 14 Setup Guide See Contrast table(2) (English) 15 Remote Control AXD7407 16 Battery Cover VNK4998 17 • • • • • • NSP 18 Polyethylene Bag Z21-038 (0.03*230*340) 19 Packing Sheet AHG7015 20 Pad L W5.1 AHA7444 21 Pad R W5.1 AHA7445 22 Packing Case See Contrast table(2) 23 Master Carton B W51 See Contrast table(2) Mark No. Description Part No. Mark No. Description XV-DV535W /WYXJ XV-DV535W /WVXJ XV-DV240 /WYXJ XV-DV240 /WVXJ XV-DV232/ WYXJ XV-DV232/ WVXJ > 1 Power Cord ADG1154 ADG1156 ADG1154 ADG1156 ADG1154 ADG1156 8 Operating Instructions ARC7580 Not used ARC7579 Not used ARC7579 Not used (Dutch/Italian/Spanish) 9 Operating Instructions ARE7355 Not used ARE7354 Not used ARE7354 Not used (English/French/German) 10 Operating Instructions Not used ARB7330 Not used ARB7346 Not used ARB7346 (English) 11 Setup Guide ARC7591 Not used ARC7589 Not used ARC7583 Not used (German/Italian) 12 Setup Guide ARC7592 Not used ARC7590 Not used ARC7584 Not used (Dutch/Spanish) 13 Setup Guide ARE7367 Not used ARE7366 Not used ARE7365 Not used (English/French) 14 Setup Guide Not used ARB7332 Not used ARB7333 Not used ARB7345 (English) 22 Packing Case AHD8334 AHD8334 AHD8326 AHD8326 Not used Not used 23 Master Carton B W51 Not used Not used Not used Not used AHD8325 AHD8355 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com XV-DV232 8 1 2 3 4 1 2 3 4 C D F A B E 2.2 EXTERIOR SECTION 6 2 1 12 3 10 19 7 5 8 14 17 20 26 16 E B F D C 11 9 23 24 22 25 21 15 28 29 29 29 29 29 29 29 29 29 29 29 29 29 29 29 29 29 29 27 13 Refer to "2.3 05 LOADER ASSY". CONTACT SIDE NON-CONTACT SIDE B C A B C A D D F E E F www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com XV-DV232 9 5 6 7 8 5 6 7 8 C D F A B E (1) EXTERIOR SECTION PARTS LIST (2) CONTRAST TABLE XV-DV535W/WYXJ, WVXJ, XV-DV240/WYXJ, WVXJ, XV-DV232/WYXJ and WVXJ are constructed the same except for the following : Mark No. Description Part No. 1 DAMP ASSY See Contrast table(2) 2 DVDMAIN ASSY See Contrast table(2) 3 FUNCTION ASSY AWU8256 4 • • • • • • > 5 POWER SUPPLY UNIT AWR7034 6 FM/AM TUNER UNIT AXX7170 7 17P FFC/60V ADD7502 8 11P FFC/60V ADD7504 9 2P Housing Wire Assy ADX7480 10 CONNECTOR ASSY PF05PP-B40 11 CONNECTOR ASSY PF13PP-C22 NSP 12 05 Loader Assy VWT1219 13 Earth Spring W5.1 ABH7240 14 Gnd Plate W5.1 ABH7241 NSP 15 Chassis W51 ANA7185 16 Rear Panel W51 See Contrast table(2) 17 Locking Card Spacer AEC7372 18 • • • • • • 19 Tray Panel W51 AAK8277 20 Front Panel Assy W51 See Contrast table(2) NSP 21 Button W51 AAD7739 22 Display Window W51 AAK8276 NSP 23 Front Panel W51 AMB7895 24 Pioneer Name Plate VAM1129 25 Leg Cushion XEB3028 26 Bonnet W51 AZN8009 NSP 27 Name Label W51 See Contrast table(2) 28 Label VRW1872 29 Screw BBZ30P080FNI Mark No. Description Part No. Mark No. Description XV-DV535W /WYXJ XV-DV535W /WVXJ XV-DV240 /WYXJ XV-DV240 /WVXJ XV-DV232 /WYXJ XV-DV232 /WVXJ 1 DAMP ASSY AWK7876 AWK7876 AWK7874 AWK7874 AWK7874 AWK7874 2 DVDMAIN ASSY AWM7995 AWM7995 AWM8003 AWM8003 AWM7983 AWM7983 16 Rear Panel W51 ANC8346 ANC8346 ANC8340 ANC8340 ANC8315 ANC8315 20 Front Panel Assy W51 AXG7259 AXG7259 AXG7257 AXG7257 AXG7252 AXG7252 NSP 27 Name Label W51 AAL7406 AAL7406 AAL7405 AAL7405 AAL7404 AAL7404 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com XV-DV232 10 1 2 3 4 1 2 3 4 C D F A B E 2.3 05 LOADER ASSY 05 LOADER ASSY PARTS LIST A A To DVDM CN101 (Pickup) To DVDM CN104 (Stepping Motor) To DVDM CN102 (Spindle Motor) To DVDM CN103 2 Refer to "2.4 TM ASSY VK1AVC." 5 4 12 23 13 17 21 16 22 15 14 22 22 22 20 19 9 1 7 10 11 6 8 8 8 8 18 24 A Lubricating Oil GYA1001 Daifree GEM1036 Refer to " Application of Lubricant". Note : Lubricating Oil GYA1001 Mark No. Description Part No. NSP 1 LOAB Assy VWG2346 2 TM Assy VK1AVC DXB1845 3 • • • • • 4 Motor Pulley PNW3026 NSP 5 Motor VXM1116 6 Flexible Cable (24P) VDA2008 7 Connector Assy 2P VKP2253 8 Floating Rubber VEB1351 9 Belt VEB1358 10 Stabilizer VNE2253 11 Loading Base VNL1917 12 Float Base 04 VNL1968 13 Drive Cam VNL1919 14 Gear Pulley VNL1921 15 Loading Gear VNL1922 16 Drive Gear VNL1923 17 SW Lever VNL1925 18 Clamper Plate 04 VNE2342 19 Bridge 04 VNE2343 20 Clamper 04 VNL1969 21 Screw JGZ17P028FTC 22 Screw VBA1094 23 Tray VNL1920 24 Clamp Magnet VMG1029 Mark No. Description Part No. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com XV-DV232 11 5 6 7 8 5 6 7 8 C D F A B E Application of Lubricant Lubricating Oil GYA1001 Around the shaft No. 11 Loading Base No. 13 Drive Cam No. 13 Drive Cam No. 23 Tray No. 23 Tray Front View Rear View Daifree GEM1036 Inner side of a ditch Concave of unevenness Top View Bottom View Daifree GEM1036 Daifree GEM1036 Side of the rib Concave of unevenness Daifree GEM1036 Concave of unevenness Daifree GEM1036 Inner side of a ditch Lubricating Oil GYA1001 Inner side of a ditch Lubricating Oil GYA1001 Lubricating Oil GYA1001 Lubricating Oil GYA1001 Lubricating Oil GYA1001 Lubricating Oil GYA1001 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com XV-DV232 12 1 2 3 4 1 2 3 4 C D F A B E 2.4 TM ASSY VK1AVC To DVDM CN101 (Pickup Assy) To DVDM CN104 (Stepping Motor) To DVDM CN102 (Spindle Motor) CONTACT SIDE NON-CONTACT SIDE 13 8 10 10 11 11 12 2 4 1 3 6 9 5 7 Silicone Adhesive GEM1037 Refer to " Application of Lubricant". Note : www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com XV-DV232 13 5 6 7 8 5 6 7 8 C D F A B E TM ASSY VK1AVC PARTS LIST Mark No. Description Part No. > 1 05SD Pickup Assy OWY8075 2 Spindle Motor N200 DXM1197 3 Guide Shaft VK1 DLA1940 4 Sub Guide Shaft VK1 DLA1941 NSP 5 Joint VK1B DNK4272 6 Joint Spring VK1 DBK1235 7 Stepping Motor VK1 DXM1201 NSP 8 Mechanism Frame VK1 DNK4160 9 Precision Screw VK1 DBA1209 10 Skew Screw VK1 DBA1211 11 Skew Spring VK1 DBH1516 NSP 12 Stepping Screw DBA1205 NSP 13 Spindle Screw VK1 DBA1210 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com XV-DV232 14 1 2 3 4 1 2 3 4 C D F A B E 3. BLOCK DIAGRAM AND SCHEMATIC DIAGRAM 3.1 BLOCK DIAGRAM RESET PDN SD OTW BE IC201 MT1389FE/C2-L-K 64M SDRAM IC202 8M FLASH IC203 16k EEPROM IC204 MOTOR DRIVER IC101 BD7995EFS LOADER MECHA A/D AK5357ET V5901 FL IC5901 PT6315 Display Driver KEY JA5901 HP 27M TUNER LINE • AUDIO PROCESSING -Audio Decode -Bass Management -Virtual Surround -Preset EQ etc. LRCK MCLK SCLK DATA1 DATA0 DATA2 SYSTEM µ-com IC5501 PDC124B LRCK MCLK SCLK SDA SCL DATA 12.288M IC3004 TC74WU04FU SCART MUTE 9V 5V EV+5V SW+6.8 +10.5 DVD POWER SW+5V +10V 5V 3.3V Vref 5V 1.8V 3.3V 9V 9V 5V DC DET PCON LINE 1.8V ATT ATT ATT -6dB -6dB -8dB SCART IC3001 HEF4052BT FL DC +/- SW+3.3V(A) SW+3.3V(B) SW+5 SW+3.3V(A) BU1924FS -25.5V DVD MAIN ASSY B FUNCTION ASSY D LOAB ASSY A FM/AM TUNER UNIT F CN5901 CN5601 CN601 CN1 CN101 CN103 B 1/4 B 2/4 CN1001 6 0 = - ~ 8 7 2 5 3 4 IC5701 IC3003 X3004 CN1 CN5701 X201 B 1/4 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com XV-DV232 15 5 6 7 8 5 6 7 8 C D F A B E HP AMP IC3901 NJM4565M Composite SCART LPF IC3601 HA17558AF FRONT L FRONT R CENTER SUB WOOFER REAR L REAR R AC IN Y/G , Cb/B , Cr/R Y , C V G , B , R Y , C V Y, Cb, Cr +B GND SW+3.3V(B) SW +6.8V +B FL DC +/- GND -25.5V LRCK MCLK SCLK DATA0 MODULATER IC3101 TAS5508APAG • frequency contorol • Channel Balance • Volume DRIVER IC3201 IC3301 IC3401 TAS5122DCA • Overheat detection • Over current VALID PWMA P PWMB P SD PWMA M PWMB M ch5 ch6 EV+ 5V RESET PDN SD OTW SDA SCL MUTE DC DET PCON HP SEL SW+3.3V(A) SW+10.5 LINE in SW+3.3V(B) SW+ 5V DATA SELECTOR V Y , C DAMP ASSY C POWER SUPPLY ASSY E IC3005 TC74VHC157FTS1 B 3/4 7 8 0 = = - 4 5 % % $ $ @ ^ 7 8 0 = - 4 5 % $ @ ^ @ ^ CN3001 CN3101 CN3002 CN3102 ~ = % $ @ ^ ~ ~ ~ CN3101 CN3001 JA451 JA403 2P: JA3111 (for XV-DV232,DV240) 4P: CN3111 (for XV-DV535W) CN2 1 08 64 08 64 2 +B GND 1 2 CN3201 CN3102 CN3002 CN3 = - 6 0 ~ 8 7 2 5 3 4 LINE out XV-DV535W Only www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com XV-DV232 16 1 2 3 4 1 2 3 4 C D F A B E 3.2 LOAB ASSY and OVERALL WIRING CONNECTION DIAGRAM CN1 CN1 PF13PP-C22 DXB1845- TRAVERSE MECHA ASSY B2P-VH S5B-PH-K-S NC-133L-H-1 B13B-PH-K-S B13B-PH-K-S OKN8001 VKN1464 52045-1145 52045-1145 52045-0745 CN2 CN601 CN602 CN1 CN3 CN1001 CN101 CN5701 CN5501 GND +B AC POWER CORD OWY8075- FOCS DRV TRKG DRV FOCS RTN FOCS DRV TRKG RTN TRKG DRV PICK UP ASSY FOCS RTN TRKG RTN LD(780) PD LD(650) GNDD LD(650) PD LD(780) GNDD VSHF GNDD VSHF GNDD SW1 GNDD SW2 LOAD+ LOAD- ST2+(B) ST2-(~B~) ST1-(~A~) ST1+(A) STEPPING MOTOR NEUTRAL LIVE Pwr-ctr GND FL DC+ -25.5V FL DC- SW+3.3V(B) SW+5.0V EV+5.0V SW+6.8V SW+3.3V(A) GND SW+10.5V ACDET TXR GND RDS VSM SW(DVD/CD) 24P FFC A VR650 B VRF VR780 VRCOM SW(DVD/CD) A VR650 B VRF VR780 VRCOM FL DC- -25.5V FL DC+ GND Pwr-ctr F VCC E VS(VREF) VS(VREF) E VCC F C D D C GND SW+3.3V(A) SW+6.8V EV+5.0V SW+5.0V SW+3.3V(B) GNDD GNDD DVD LOADER V+5S U- V+ U+ HB V W+ V- U W- SPINDLE MOTOR INSIDE W VWT1219- ACDET SW+10.5V TXR VSM RDS GND AM FM TXL DO DI CE GND CLK +9V 11P FFC ADD7504- +9V CLK CE DI DO TXL GND STBY WEN/DI RST WDD WCLK NC VCC VSS µ-COM DOWNLOAD 2 1 23 22 21 24 19 20 16 17 15 14 18 5 1 2 2 1 3 4 2 1 9 10 13 11 12 13 11 12 9 10 4 5 6 7 8 3 7 8 5 6 3 4 2 1 2 1 8 11 9 10 13 11 10 9 8 12 3 4 5 7 6 2 1 3 4 7 5 6 1 2 4 1 6 5 2 7 3 LOADING MOTOR ASSY : VXX2912 A B B B ( 1/4- 4/4)DVD MAIN ASSY (AWM7983:XV-DV232) (AWM8003:XV-DV240) (AWM7995:XV-DV535W) LOAB ASSY (VWG2346) A POWER SUPPLY UNIT (AWR7034) E No schematic Diagram FM/AM TUNER UNIT (AXX7170) F www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com XV-DV232 17 5 6 7 8 5 6 7 8 C D F A B E AKB7114 FLCS FLCK FLDATA VFDP FLDC+ FLDC- KEY2 REMOCON KEY1 GNDD GNDD VE+5 HP_L GNDD HP_R HP_DET HPMUTE CN3111 HEAD PHONE PF05PP-B40 B5B-PH-K-S VKN1235 B2P-VH AKE7115- AKP7199-A VKN1243 AKP7199-A AKM7077- AKM7077- AAV7104- 52045-1745 52045-1745 RKB1041 AKN7005- VKB1122 B4B-PH-K-S VKB1157- CN103 CN104 CN3201 CN3211 CN3002 CN102 CN3001 CN3102 CN3101 V5901 CN5901 CN5601 JA3111 JA5901 JA403 CN204 JA451 SW1 GND LOAD- LOAD+ SW2 GNDD GND GND GND GND RECMUTE SOUTR SOUTL LINR LINL 4P FFC ST1+(A) ST1-(~A~) ST2-(~B~) ST2+(B) SDA3 SDA2 GND SCLK SDA1 GND LRCLK MCLK GND GND GND +B LINL GND GND GND RECMUTE GND SOUTR SOUTL LINR SDA3 SDA2 GND SDA1 SCLK GND GND MCLK LRCLK SW- SW+ RL- FL+ FL- RL+ C+ C- 6ch SP OUT FR- FR+ RR- RR+ V+5S U+ V+ U- GND GND POWER GND SCL XSD XOTW 12P FFC HB W- U V- W+ V 3.3V SDA GND HPR GND XPDN GND XRST XMUTE INSIDE W PCON HPL XHPSEL XSD XOTW GND POWER GND GND SCL 3.3V XRST GND XPDN GND HPR GND SDA XMUTE XHPSEL PCON HPL FL ADD7504- 17P FFC GNDD TVOUT_L TVOUT_R TVIN_R TVIN_L HP OUT COMPOSITE V NC GND VIDEO OUTPUT STBY for DOWNLOAD EURO CONNECTOR NC R/C BLANK GND GND GND V/Y GND G GND R OUT R IN B L OUT GND GND L IN SQUEEZE NC 5 1 1 3 4 2 3 10 2 5 9 7 4 8 6 4 1 3 2 15 16 14 19 11 13 17 18 12 1 1 2 6 5 4 3 10 9 8 7 2 11 12 15 18 16 13 14 19 17 12 11 5 8 9 6 7 10 2 1 3 4 2 3 4 1 7 2 1 5 6 4 3 5 8 9 6 7 10 8 16 13 14 12 15 10 11 9 12 11 19 18 17 2 6 5 7 1 4 3 12 16 10 9 8 15 13 14 11 19 17 18 4 3 2 1 16 9 10 14 11 12 17 15 5 13 8 7 6 9 HP_R HP_L GNDD HPMUTE GNDD VE+5 REMOCON KEY1 FLDC- FLDC+ KEY2 HP_DET VFDP FLCK FLDATA FLCS 4 3 2 1 12 8 6 5 13 14 11 17 7 15 16 10 21 20 1 2 4 3 12 11 10 17 18 15 16 19 13 14 1 2 8 7 6 5 9 4 3 except EURO model & EURO WIRELESS model ONLY C C C ( 1/2- 2/2)DAMP ASSY (AWK7874:XV-DV232) (AWK7874:XV-DV240) (AWK7876:XV-DV535W) D FUNCTION ASSY AWU8256 ÷ When ordering service parts, be sure to refer to "EXPLODED VIEWS and PARTS LIST" or "PCB PARTS LIST". ÷ The > mark found on some component parts indicates the importance of the safety factor of the part. Therefore, when replacing, be sure to use parts of identical designation. ÷ : The power supply is shown with the marked box. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com XV-DV232 18 1 2 3 4 1 2 3 4 C D F A B E 3.3 DVD MAIN ASSY (1/4) LIMIT 2 3 1 8 6 7 4 5 48 47 46 45 44 41 42 43 11 10 12 9 13 15 16 14 20 21 17 19 18 22 23 24 40 38 39 37 34 35 36 33 30 32 28 31 29 27 25 26 5 3 4 1 2 4 3 2 1 1 2 3 6 8 4 7 5 1 2 3 4 5 42 43 44 40 39 38 37 41 6 7 8 9 10 11 12 24 22 23 20 21 18 19 17 16 15 14 5 2 1 6 7 5 3 2 4 8 1 63 62 64 66 65 68 67 70 71 69 61 60 59 56 57 58 53 54 55 9 10 11 12 14 15 16 13 18 19 21 20 17 22 33 35 34 36 31 30 32 29 26 27 24 25 28 23 51 50 52 47 48 49 45 44 46 41 43 42 39 38 40 36 35 37 33 32 34 30 31 29 28 26 27 23 25 24 22 21 20 18 17 19 7 15 16 11 14 8 12 9 10 13 4 6 5 3 2 1 253 256 254 255 252 250 251 13 12 10 11 9 8 4 3 7 6 4 5 2 3 1 Main:S29AL016D70TFI010-K A13 A15 A14 A8 A12 A10 A11 A9 ~BYTE~ A16 VSS D6 D7 D15 D14 A19 ~WE~ NC ~RESET~ NC NC A18 RY/~BY~ A7 A17 A6 A4 A5 A2 A3 A1 D12 D5 D13 D4 VCC D10 D3 D11 D2 D9 D0 D8 D1 VSS ~OE~ A0 ~CE~ Main:S-24CS04AFJ-TBB IOWR# CHASSIS GND SW1 GNDD SW2 LOAD- LOAD+ to LOAB ASSY ST1-(~A~) ST1+(A) ST2+(B) to STEPPING MOTOR ST2-(~B~) LDOP FCO+ LDON TKO+ FCO- AGND AVM TKO- SERVO DRIVER (ROHM) V+5S U- U+ V+ V- VCC HU+ HU- HV+ HV- HB HW+ HW- W+ W- U HB W V to SPINDLE MOTOR INSIDE FOCS RTN TRKG RTN FOCS DRV TRKG DRV VSHF LD(650) GNDD LD(780) PD VR780 GNDD WP GND NC NC VCC NC DVSS APLLVSS APLLCAP HIGHA6(PU) HIGHA4(PU) HIGHA5(PU) IOA19 (PU) IOA18 (PU) HIGHA0(PU) IOA5 (PU) IOA6 (PU) IOA7 (PU) IOA4 (PU) IOA3 (PU) IOA2 (PU) 67:A16 68:HIGHA7(PU) 66:XIOWR 65:APLLVSSVDD3 DVCC TKIN FCIN LDIN SLVDD SLGND SLO1N SLO1P SLIN2 SLIN1 SLRNF2 SLO2N SLO2P SLRNF1 U SPGND1 V SPVM1 W SPGND2 SPVM1 SPRNF CTL1 CTL2 DGND FG SPIN VC DVDD18 TDO/V_ADIN7 (JTAG) TCK/V_ADIN6 (JTAG) FG/V_ADIN8 (PU) TMS/V_ADIN5 (JTAG) TDI/V_ADIN4 (JTAG) USB_VDD3 USBM USBP USB_VSS TRO FOO PWMOUT1/V_ADIN9 TROPENPWM FMO OP_INP OP_INN DMO OP_OUT TEZISILV TEO FEO VREFO V2O V2REFO RFLV/RFON CSO/RFOP SGND (1/2) (2/2) (1/2) LDO2 SVDD3 LDO1 MIDI2 MIDI1 TPI TNI CDFON CDFOP DVDRFIN MD MC SA MB MA SD SC SB IREF:255 RFGC:254 AVDD3:256 OSP:252 OSN:253 DVDRFIP DVDD DVDC AGND DVDA DVDB CEQP CEQN SW (DVD/CD) VR650 VRCOM A B VRF D C VCC E F VS(VREF) GNDD to PICK UP (2/2) PWR# PCE# A14 A15 A16 A10 A12 A9 A11 A13 ALE IOWR# IOCE# INT0# URD# UWR# UP3_1 A17 A0 AD7 AD6 PWR# A20 A19 A6 A7 A5 A18 A8 A3 A2 A4 AD1 AD0 PRD# AD2 AD3 AD4 AD5 PCE# A1 PWR# A14 A16 A15 A13 A12 TROUT TRIN LOAD+ LOAD- F- LOAD- LOAD+ F+ T+ T- ST1+ ST2+ ST1- ST2- HU+ HU- HV+ HV- U HW+ W V HW- HW- HW+ HU- HV+ HU+ HV- F+ T- F- T+ SDA SCL ST2- ST1- ST1+ ST2+ TRSO TROPEN FOSO FMSO PWMOUT1 A6 A2 A19 A8 A5 A4 A7 A3 A18 TRIN TROUT STBY FG ENDM TRSO FOSO PWMOUT1 FMSO TROPEN DMSO DMSO ENDM STBY FG U W V F E MDI1 LDO1 LDO2 LDO2 B VRF C A D LDO1 MDI1 A B IOA VRF D C E F IOA R284 R285 IC203 C289 C296 R282 KN103 CN103 C153 C152 C151 C103 CN104 R131 R133 R132 R136 R134 C133 R135 C101 R100 IC101 C140 C102 C141 C142 C143 CN102 C371 R318 R219 R218 R208 R151 R152 R154 R153 C104 C121 IC204 C290 R232 C221 C220 R216 C219 R217 C217 C131 C132 R214 C144 C161 C209 C212 C145 C146 C208 C210 C211 R210 R211 R215 R212 R213 C218 C216 R205 R206 R202 R204 R201 C206 C214 C204 C205 C213 C203 C215 Q307 Q307 R322 R325 C309 L308 L309 Q308 C310 C345 C347 C344 C343 C346 C207 C291 C202 C201 C272 R372 R374 Q305 R315 R313 R314 Q304 R371 R375 C372 C373 CN101 C374 R326 R321 R310 C320 Q308 R200 C273 R207 C271 R256 C270 STBY GNDD 10k GNDD STBY Sub:MBM29LV160TE70PFTN-K V+3D GNDD FLASH V+3D 1 1000p STBY Sub:BR24L04FJ-W-TBB B5B-PH-K-S 0.01 0.01 0.01 YB YB YB GNDM GNDD VKN1235 STBY 4.7 4.7 4.7 4.7 4.7 4.7 1 100/10 STBY BD7995EFS 1 V+5S V+6R8 1 STBY STBY STBY GNDD VKN1243 0.1 100K 10K 10K STBY V+3D V+3 1.8 1.8 1 1 1 V+5M EEPROM 0.1 STBY STBY 0.1 STBY 1500p STBY 0.1 1 0.1 STBY STBY 2200p 2200p 1000p V1P4 0.1 2200p YB YB YB V20 2200p 2200p 56p V1P4 STBY STBY STBY 10K 10K STBY 0.1 180k 220k 22K 22K 56p 1.5K 47/35 0.1 0.1 0.1 0.1 47/35 47/35 HN1A01F(YGR)-T HN1A01F(YGR)-T 4.7 4.7 47/35 STBY STBY HN1A01F(YGR)-T GNDD 47/35 0.1 1 1 1 1 1 220/6.3 470/6.3 220/6.3 STBY STBY UM5K1N-TRB GNDD 10K 100K 2SC4081(QR)-TLB 10K STBY STBY 0.1 100/6.3 V+5S V+5S VKN1464 0.1 V20 4.7 4.7 STBY HN1A01F(YGR)-T STBY V+3 STBY V+1R8 0.1 STBY 0.1 15k 0.1 STBY V+3 V+3RF AYW7059 B 1/4 TRAVERSE MECHA ASSY CN1 SPINDLE MOTOR STEPPING MOTOR (RF) (T) (T) (F) (F) (S) (S) (S) (S) 4 3 1 2 LD Driver for CD LD Driver for DVD FTS Driver FLASH (T) (F) (T) (F) (RF) : VIDEO SIGNAL ROUTE (S_Y) : VIDEO SIGNAL ROUTE(C/V) (S_Y) : VIDEO SIGNAL ROUTE (S_C) : AUDIO DATA SIGNAL ROUTE (S_C) : VIDEO SIGNAL ROUTE (R/Cr) (R/Cr) : VIDEO SIGNAL ROUTE (G/Y) (G/Y) : VIDEO SIGNAL ROUTE (B/Cb) (B/Cb) (AD) : FOCUS SERVO LOOP LINE : TRACKING SERVO LOOP LINE : STEPPING SERVO LOOP LINE (F) (RF) : RF SIGNAL ROUTE (T) (S) (C/V) CN601 A www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com XV-DV232 19 5 6 7 8 5 6 7 8 C D F A B E LIMIT UCOM AUDIO VIDEO 1 2 4 3 73 72 74 77 75 76 81 80 79 78 83 82 86 85 84 89 88 87 90 91 92 93 94 99 98 95 96 97 102 101 100 103 106 105 107 104 109 111 110 112 108 116 115 113 114 118 117 120 119 124 125 121 122 123 128 126 127 131 130 129 133 132 140 138 139 136 137 134 135 148 145 144 147 146 149 141 142 143 151 150 154 155 156 157 158 153 152 166 165 167 164 159 160 161 162 163 248 249 245 247 246 244 240 243 242 241 237 239 238 235 236 234 231 232 233 172 176 174 175 171 170 169 168 173 184 185 182 183 177 181 180 178 179 186 228 227 230 229 226 223 222 225 224 219 220 218 221 211 217 214 212 213 216 205 208 210 207 215 206 209 189 187 188 191 190 192 201 202 204 203 199 200 197 198 196 194 195 193 54 1 53 52 51 50 49 48 44 45 47 46 3 4 2 5 6 7 9 8 10 11 41 42 43 38 40 39 36 37 35 13 12 14 17 15 16 18 19 20 34 33 32 29 30 31 28 23 21 22 25 24 26 27 STBY : 1608Size CCSR**~ CKSR**~ CAPACITOR : 2125Size CKSQ**~ : 1608Size RS1/16S~ RS1/10S~ Chip Size : 2125Size RESISTOR HIGHA3(PU) DVDD3 HIGHA1(PU) HIGHA2(PU) IOA20 XIOCS (PU) AD0 AD1 DVDD3 XIOOE IOCA1 (PU) DVSS (18) AD4 AD3 AD2 AD5 ALE (PU) AD6 IOA2/V_ADIN0 AD7 A17 XUWR (PU) DVSS (3) IOA0 (PU) XURD (PU) UP1_3 (PU) UP1_2 (PU) DVDD18 UP1_5 (PU) UP1_6 (PU) UP1_4 (PU) UP1_7 (PU) UP3_4 (PU) UP3_5 (PU) UP3_1 (PU) UP3_0 (PU) DVDD3 IR ICE (PD) XINT0 (PU) XPRST (PU) DVSS (18) DQS0 DQM0 RD7 RD6 DVSS (3) RD3 RD4 RD5 DVDD18 RD0 RD1 RD2 RD11 RD13 RD12 DQM1 XRWE DQS1 XCAS XRAS 128:RD14 127:DVDD3 126:RD15 RD8 RD10 (3)DVSS RD9 (3) DVSS RA10 RA0 RA1 XRCS DVDD3 (18) DVSS BA0 BA1 RA11 RA2 RCLK CKE DVDD18 RVREFN_ADIN3 RCLKB DVDD3 RA3 RA9 RA8 DVDD3 (PU)RD3/ASDATA5 RA4 (18) DVSS (3) DVSS RA7 RA6 RA5 RFGND CRTPLP RFRPDC RFVDD3 RFRPAC HRFZC S_VCM ADCVDD3 ADCVSS S_VREFP S_VREFN LPFON LPFIP LPFOP LPFIN PLLVDD3 JITFN IDACEXLP PLLVSS DVDD18 RD27 RD28 RD26 (3) DVSS (PU) RD30 RD29 (INPUT ) RD24 RD25 RD23 (INPUT PU) RD18 DACVDDC:189 VREF:190 DVDD3 (INPUT PU) RD21 RD22 (INPUT PU) RD20 (INPUT PU) RD19 (INPUT PU) DQM3 (INPUT PU) DQM2 (3) DVSS (PD) ASDATA4 (PD) ASDATA3 (PD) ASDATA2 (PD) ASDATA1 JITFO XTALI RFGND18 XTALO RFVDD18 SPDIF MC_DATA DVDD18 (18) DVSS (PD) ASDATA0 DVDD3 YUV7/ASDATA5 YUV0/CIN:192 YUV3/CVBS (INPUT PU) RD17 (INPUT PU) RD16 FS:191 YUV6/R DVDD3 YUV4/G DACVSSA YUV5/B YUV2/C DACVSSB DACVDDA DACVDDB YUV1/Y DACVSSC CHASSIS GND VSS VCC VSSQ DQ14 DQ15 DQ12 DQ13 VCCQ VSSQ DQ11 DQ10 VCCQ DQ1 DQ0 DQ3 VSSQ DQ2 VCCQ DQ4 DQ5 DQ9 DQ8 VCCQ VSS NC UDQM CKE NC CLK DQ6 DQ7 VSSQ LDQM WE VCC CS RAS CAS A11 A9 A8 A6 A7 A5 VSS A4 A10/AP BA0 BA1 A2 A0 A1 A3 VCC 30 A11 A1 PCE# A20 A9 A10 PRD# IOCE# AD1 AD0 AD4 AD3 AD2 ALE AD5 AD7 AD6 25 24 23 67 96 A0 UWR# A17 URD# SDA SCL UP3_1 INT0# TXD RXD DQM0 DQ7 DQ6 DQ3 DQ4 DQ5 DQ0 DQ2 DQ1 DQ14 DQ15 DQ12 DQ11 DQ13 DQ10 DQ9 DQ8 DQM1 DRAS# DWE# DCAS# DCS# DBA0 DQ15 DQ14 MA10 DBA1 DQ13 DQ12 MA0 MA1 DQ11 DQ10 DQ6 DQ7 DQ5 DQ4 DQ2 DQ3 MA2 MA3 DQ9 DQ8 DQM1 SDCLK SDCKE MA11 DQ0 DQ1 DQM0 DWE# DCAS# DRAS# DCS# MA8 MA9 MA8 MA9 MA11 MA7 MA6 MA6 MA7 MA5 MA5 MA4 MA4 DBA1 DBA0 MA10 MA2 MA0 MA1 MA3 I/XP LETTER SQUEEZE VSEL2 VSEL1 ASDAT2 ASDAT1 ASDAT0 ALRCK ABCK ACLK R_CR B_CB CVBS S_Y S_C G_CY OEICG IOA R5201 R5202 R5203 R5204 R5206 R5205 CN204 R233 R224 C222 C223 R237 R221 R258 R260 R259 R261 R234 R223 C224 R235 C227 C225 C226 R220 R236 R239 C228 C230 IC201 C269 C268 C261 R225 KN202 C286 C231 R226 R227 C285 C287 C232 C233 R229 R228 C284 IC202 C288 C234 C235 R250 R262 C281 C282 R281 C283 R263 R265 R264 C236 C244 C242 C243 R280 R279 C237 C266 C267 C259 C258 C257 C260 C256 C265 C264 R255 C263 C255 R254 C262 C254 R251 C251 X201 C253 C241 R257 R246 R244 R245 R249 R247 R238 C240 R243 R241 R242 C247 C248 C239 C246 C245 R252 R253 C252 R209 GNDD 3.3K GNDD 6.8K B4B-PH-K-S GNDD 3.3K 6.8K 6.8K 3.3K V+3D 0 33 0.1 0.1 33 33 33 33 33 33 33 33 0.1 4.7k 220p 0.1 0.01 STBY STBY STBY 0.1 1000p MT1389FE/C2-L 0.033 STBY GNDD RAB4C330J-T 33*4 GNDD STBY 0.1 0.1 33 33 0.1 0.1 K4S641632F-TC75-K 0.1 STBY 0.1 33 0.1 64M S 0.1 0.1 STBY 0.1 STBY 220/6.3 STBY 1 0.1 STBY STBY STBY 0.1 V+3D V+3DR 0.1 GNDD STBY 1 220/6.3 560F STBY 0.1 1000p 0.1 0.047 0.047 0.1 0.1 STBY 750K 100K 22p 10/50 0.47 STBY STBY 390p 100K V1P4 9p VSS1168 GNDD 0.1 0.1 STBY 10K 10K 10k 0.1 0.1 0.1 0.1 STBY 33 33 33 680 STBY STBY 10 33 33 10p STBY V+3 V+3V 2-A4,3-A2 560F R279 2.2kF ONLY model EURO *1 model except EURO B 1/4 DVD IC 14 12 11 13 (AD) (R/Cr) (G/Y) (C/V) (S_C) (S_Y) (B/Cb) (AD) B 1/4 DVD MAIN ASSY (AWM7983:XV-DV232) (AWM8003:XV-DV240) (AWM7995:XV-DV535W) SDRAM (64M) B 2/4,3/4 B 4/4 B 3/4 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com XV-DV232 20 1 2 3 4 1 2 3 4 C D F A B E 3.4 DVD MAIN ASSY (2/4) HP_L HP_R XTVMUTE 59 60 58 7 17 18 19 2 31 27 28 25 24 23 21 22 19 17 7 6 4 4 3 1 2 32 34 SEL POW 31 30 41 52 58 60 59 64 66 61 67 62 65 71 70 18 72 75 76 77 79 74 96 94 84 16 17 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 C E B E B C 1 2 3 31 32 35 34 33 28 29 30 27 26 37 36 39 38 42 40 41 43 44 45 48 46 47 49 50 53 52 51 54 55 24 25 22 23 20 21 57 56 59 58 60 61 4 3 1 2 5 8 6 7 19 18 15 17 16 14 13 62 63 65 66 64 67 68 12 11 10 9 7 8 69 70 71 72 73 74 5 6 4 3 2 1 76 75 78 77 79 80 4 5 4 6 2 7 5 3 1 100 99 96 97 98 94 92 93 95 91 90 89 86 88 87 85 84 83 81 82 KN5601 C5609 C5608 C5607 C5606 C5604 C5605 R3952 R3951 C801 D801 R821 R822 Q801 R824 R801 Q821 R823 D852 R852 Q821 R851 D861 L3951 C3953 L3952 R3953 R3954 C3951 C3952 CN5601 C3954 R3955 Q3951 C5525 C5524 Q5525 R5524 R5523 R5529 C5519 C5522 C5523 R5521 R5522 R5513 R5515 R5516 R5525 R5514 C5521 R5512 R5519 R5517 C5517 C5591 R5509 X5501 C5508 C5509 R5506 R5505 R5507 R5508 R5503 R5504 C5502 R5502 R5501 R5543 R5544 R5553 R5554 C5549 R5530 R5541 C5539 R5549 R5550 R5551 R5548 C5556 IC5503 C5550 R5552 R5557 R5511 IC5501 C5518 C5577 R5561 R5567 R5566 R5518 R5568 R5520 R5570 R5573 R5580 R5579 R5578 IC5502 R5590 C5590 CN5501 R5597 R5592 C5582 R5584 C5579 R5583 R5581 R5582 C5581 KN5501 3-A1 3-A1 4-C5 STBY VFDP GNDD FLDC- FLDC+ STBY 1000p 1000p 1000p 1000p 1000p GNDD STBY UDZS4.7B 10k 4.7k DTC124EUA-TLB 10k HN1A01F(YGR)-T 4.7k 15k 1SS355 HN1A01F(YGR)-T 47k 10k 1SS355 STBY STBY STBY 47k 47k STBY STBY 100/16 STBY 100/16 VE+5 52045-1745 GNDD DTC124EUA VE+5 1.8k STBY GNDD DTC143EUA VE+5 10/50 47k RAB4C221J-T STBY GNDD 0.01 VU+5 0.01 STBY 0.01 220 * 10k * 220 1M 220 0.01 STBY * VE+5 GNDD 0.01 * STBY 2.2K ASS7034 10MHz 0.01 RAB4C221J-T VU+5 STBY STBY 100k 1000p V+3 V+6R8 V+5V V+5V GNDD RAB4C221J-T 10k 10k RAB4C221J-T 47k 47K V+6R8 GNDD 47p 0.1 VE+5 220 220 220 220 GNDD 220 0.1 Main:S-93C46BD01-J8T1 0.1 VE+5 220 RAB4C221J-T 0.1 0.01 220 10k 220 0.01 0.01 RAB4C221J-T 220 220 220 STBY RAB4C221J-T 10k RAB4C221J-T STBY 220 STBY VE+5 STBY VE+5 GNDD 15K STBY 52045-0745 VE+5 STBY 0.1 RAB4C221J-T RAB4C221J-T 100/6.3 STBY STBY STBY VE+5 STBY CHASSIS GND to DISPLAY FLDATA FLCK FLCS FLDC- VFDP VE+5 FLDC+ GNDD REMOCON GNDD KEY1 VDET (2/2) VDET (1/2) KEY2 HP_DET GNDD HP_L HPMUTE HP_R RESET DESTINATION MODEL TEST POINT SHORT for STEST UTEST GND DO XREADY (SYS_CS2) NC DASCL DASDA VSS4 NC NC NC VDD4 (ATT10dB) NC STEST UTEST NC NC TXCE EEPSK NC NC NC SCLK XHP MUTE SDATA MDATA NC PCONFIG XPROTECT EEPCS NC XRECMUTE NC SELPOW EEPDO EEPDI VDD2 VSS2 (XFLRST) FLCS TXCLK FLCLK FLDAT DI SK NC TEST CS Sub:BR93L4RFJ-W EEPROM VCC NC KEY2 VDET MODEL VDD1 SIMUKE µ-COM PDC124 TXODAT NC RDSDATA RDSPOW TXIDAT DVDACK CF2 CF1 XT2/AN11 VSS1 REMOCON XT1/AN10 XRESET (XSYSMUTE) (PWRERR) (PWRCONT1) PWRCONT2 (XVMUTE) KEY1 XDARST XDAPDN (FREQCONT2) XDAMUTE (PSVC) P_ON RDSCLK NC HP SEL ACDET XDVDRST XTVMUTE DVDPOWER HP DET FLASH CLK FLASH DO FLASH E/D TXPOWER NC VSS3 VDD3 NC NC NC NC INPUTSELB INPUTSELA ADPDN SHUTDWN (DC DET) (FREQCONT1) (FLCONT) XOTW DOWNLOAD micro-COM RST NC VSS VCC WDD WCLK STBY WEN/DI CHASSIS GND to DVD/ANALOG INPUT PART (Page 1/4,3/4) A B 2/4 CN5901 D 3/4 B 4/4 B * XV-DV232 XV-DV240 XV-DV535W R5513 47k 47k 47k R5516 R5515 R5514 47k 47k 47k 47k www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com XV-DV232 21 5 6 7 8 5 6 7 8 C D F A B E UCOM 84 4 ACDET 1 22 13 4 5 3 1 2 C2 B E E2 CB2 2 3 9 10 11 12 4 5 6 7 8 1 3 2 1 R1001 KN1001 C1103 C1102 R1104 R1102 R1103 IC1101 C1101 C1501 C1505 C1502 D1501 R1101 L1501 Q1304 C1202 R1202 C1201 R1204 Q1202 Q1201 R1203 R1305 L1305 R1304 R1303 Q1302 R1201 C1203 D1410 C1415 D1415 Q1410 C1413 D1412 R1411 Q1410 R1410 R1415 Q1413 R1404 R1402 R1403 D1401 R1401 Q1303 R1302 R1301 Q1301 CN1001 Q1401 D1402 Q1401 R1406 R1405 R1407 1-D6,3-A2 GNDM GNDD STBY FLDC- FLDC+ VFDP STBY 47/35 STBY 33kF 33kF 33kF V+1R8 BA3948FP GNDD 1 GNDD 100/10 0.01 0.1 STBY STBY 22u DTC143EUA-TLB VU+5 VE+5 GNDD GNDD 120 STBY 1 STBY 2SB1689-TLB V+3 DTC143EUA-TLB STBY VTL1095 560 47k 2SB1689-TLB GNDD 47K STBY STBY V+5M V+5S V+5 V+5V VFDP GNDD GNDD UDZS15B GNDD STBY UDZS4.7B UMD2N-TLB STBY 1SS355 UMD2N-TLB 10k 10k 470 DTC124EUA-TLB DAN202U-TLB V+5 HN1A01F(YGR)-T 10k GNDD 47K 10k 15k V+3R3 DTC143EUA-TLB B13B-PH-K-S V+6R8 560 47k 2SB1689-TLB V+10 1SS355 V+3R3 HN1A01F(YGR)-T GNDD 12k V+10 V+5 10k 4.7k V+5 V+10 CCSR**~ : 2125Size CKSQ**~ CKSR**~ CAPACITOR : 1608Size RESISTOR Chip Size RS1/16S~ : 2125Size : 1608Size RS1/10S~ FL PCB BINDER: VEF1040- CHASSIS GND -25.5V from SUB POWER SUPPLY PWRCONT2 DVDPOWER µ-com FL DRIVER BACK END IC BACK END IC SDRAM FLASH ROM µ-com FTS DRIVER PU VIDEO DRIVER INPUT SELECTOR POWER SUPPLY SCART XPROTECT (2/2) (2/2) FL DC- FL DC+ GND Pwr-ctr DATA SELECTOR A/D SW+3.3V(A) SW+3.3V(B) GND SW+5.0V SW+6.8V FTS DRIVER ACDET EV+5.0V SW+10.5V SCART AUDIO BUFFER PROTECT (2/2) (1/2) B 2/4 B 2/4 DVD MAIN ASSY (AWM7983:XV-DV232) (AWM8003:XV-DV240) (AWM7995:XV-DV535W) 1/4, 3/4 B CN3 E www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com XV-DV232 22 1 2 3 4 1 2 3 4 C D F A B E 3.5 DVD MAIN ASSY (3/4) SCART_R SCART_L TVOUT_R TVOUT_L HP_R HP_L UCOM 66 61 62 52 32 BCKO LRCKO MCKO ASDAT2 DATA0 ASDAT1 84 79 77 65 75 64 74 6 28 71 27 72 70 3 21 C5705 C5704 C5709 C5701 C5702 C5703 R5719 C5707 R5705 C5708 R5718 R5717 Q5703 C5716 C5713 R5708 C5719 R5710 IC5701 C5715 C5720 X5701 C5714 C5712 CN5701 R5712 R5713 R5716 R5715 R5714 R5707 Q5703 R5702 R5701 C3019 C3020 R3016 C3016 Q3006 R3006 R3015 C3015 R3005 R3004 C3012 R3012 R3003 R3011 C3011 CN3002 KN3001 R3002 R3082 C5706 R5704 R5706 R5703 R3020 Q5701 R3019 R3018 R3017 R3014 R3013 C3004 R3010 Q3005 C3002 C3001 IC3001 R3022 R3040 C3022 R3024 R3026 C3024 R3025 R3081 R3001 CN3001 R3007 C3003 R3009 Q3005 R3021 R3039 R3023 C3023 C3021 11 10 8 9 7 5 6 3 4 E2 B2 C2 6 7 8 3 5 4 1 2 9 10 11 13 12 14 15 16 1 2 E B C 6 5 4 3 2 1 10 9 8 7 13 11 12 15 16 14 19 17 18 5 4 3 2 1 1 2 3 4 5 6 8 7 14 16 15 11 13 12 9 10 6 10 9 8 7 11 15 16 13 14 17 18 12 19 4-C5 4-C5 4-C5 4-C5 2-C2 2-D2 1-D6,2-A4 GNDD STBY STBY STBY STBY 100p STBY 100p STBY 1000p 47/35 CH CH STBY STBY STBY HN1C01FU 560p 4700p CH 0 10/50 GNDD 100 BU1924FS GNDD 0.01 47/35 ASS7004 CH 27p CH 33p 52045-1145 2.7k 2.7k STBY STBY STBY HN1C01FU 2.7k GNDD V+10 10/50 2.7k 10/50 10/50 GNDD 10/50 DTC124EUA-TLB 10k VE+5 100 100 10/50 10/50 47 AKP7199-A STBY STBY 1M STBY STBY STBY STBY 47k V+5 STBY 47k 22k VREF V+5 22k 22k 22k VREF 22k 22k 22k VREF 22k VREF Main:HEF4052BT-TBB 1k HN1A01F(YGR)-T STBY 0.01 GNDD STBY 220k 1k 15k 0.1 GNDD V+10 47/35 1k 1k 1M STBY AKP7199-A V+3R3 0 V+5 1k HN1A01F(YGR)-T 220k STBY VREF 15k V+5 1k GNDD 47/35 V+10 0.1 to TUNER MODULE GND RDS VSM TXR +9V TXL DO CLK GND VSS1 VDD1 VSS2 VDD2 CMP VSS3 T1 T2 (2/2) RDS VREF XI XO QUAL RDSDATA RDSCLK NC 4.322MHz CE DI RECMUTE GND GND GND RECMUTE SOUTR SOUTL GND GND GND LRCLK SCLK LINR LINL GND SDA3 SDA2 MCLK GND SDA1 to D-AMP/SMPS CHASSIS GND XSD XOTW GND POWER GND PWRCONT2 TUNER TV L H H H (1/2) RDS RDS DATA INPUTSELA RDSPOW INPUTSELB RDSCLK Sub:TC4052BFN-TBB Y2 Y0 Y(Rch) INH Y3 Y1 VSS VEE VDD X(Lch) X1 X2 X0 X3 A B (2/2) GND SCL SDA GND XMUTE XPDN L H - SCART L L A FUNCTION B SELECTOR HPL XHPSEL GND 3.3V GND XRST HPR AUDIO INPUT PCON from Ucom PART (Page 2/4) (1/2) A B 3/4 B 3/4 DVD MAIN ASSY (AWM7983:XV-DV232) (AWM8003:XD-DV240) (AWM7995:XV-DV535W) C 1/2 CN3101 C 1/2 CN3102 F CN1 B 4/4 B 4/4 B 2/4 B 1/4, 2/4 Analog Input Selector Analog Audio Buffer (AD) (AD) DV535W only www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com XV-DV232 23 5 6 7 8 5 6 7 8 C D F A B E AUDIO DATA0 ASDAT0 ADDATA ADLRCK ALRCK LRCKO 94 41 34 MCKO ACLK ADMCK1 BCKO ADBCK ABCK 76 ADMCK1 ADMCK0 ADDATA ADMCK0 ADLRCK ADBCK R3063 R3062 R3061 C3026 R3028 R3030 R3027 Q3030 Q3042 R3047 R3702 R3042 R3034 R3032 C3032 Q3041 R3046 C3045 C3046 Q3032 R3035 R3031 R3041 C3041 R3045 C3043 C3042 C3044 R3066 R3065 R3064 C3064 IC3005 C3056 C3057 R3056 X3004 R3055 R3054 R3053 R3052 C3052 IC3004 C3048 R3073 R3051 R3050 R3048 R3049 C3025 R3029 Q3031 R3033 C3031 R3701 IC3003 B E C B E C E B C 9 8 7 10 5 6 12 11 2 4 3 14 13 15 1 16 4 5 1 3 2 8 6 7 8 9 6 7 11 10 3 4 5 14 13 12 1 2 15 16 1-A6 GNDD 220 220 220 GNDD GNDD 10/50 STBY 47k DTA124EUA-TLB DTC124EUA-TLB STBY 10/50 STBY 10K **** 10k STBY 2SA1576A(RS)-TLB STBY 10/50 0.1 2SC4081(QR) 0 10k 10/50 STBY V+3R3 0.1 2.2/50 0.1 100 TC74VHC157FTS1-TBB 220 STBY 0.1 V+3R3 CH CH33p 27p GNDD 12.288M 100 VSS1140 1M GNDD 100 TC7WU04FU-TRB 100 0 0.1 3.3k 0.01 100 100 1.8k 100 10/50 47k STBY 2SC4081(QR) *** 10/50 V+5 STBY AK5357ET-TBB : 1608Size CCSR**~ : 2125Size CKSQ**~ CKSR**~ RESISTOR CAPACITOR RS1/16S~ : 2125Size : 1608Size RS1/10S~ STBY SEL POW TXPOWER ATT10dB Chip Size GND ST VCC ADPDN GND VCC DGND VD SDTO LRCK VA AGND MCLK SCLK CKS1 VCOM DIF PDN AINL AINR CKS0 CKS2 STBY STBY 10dB ATT A/D from DVD PART (Page 1/4) B 3/4 B 1/4 (AD) (AD) (AD) (AD) Digital Input Selector DVD Audio Data A/D Data ( ) AD Master Clock Oscillator (AD) (AD) : AUDIO DATA SIGNAL ROUTE ↔ www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com XV-DV232 24 1 2 3 4 1 2 3 4 C D F A B E 3.6 DVD MAIN ASSY (4/4) VIDEO (2/2) (1/2) (1/2) (2/2) from DVD PART (Page 1/4) 0 0 0 0 0 0 E B C C2 E2 B2 B B2 E C C2 C B E E2 C469 R463 R465 Q461 R461 R462 Q461 C465 C464 R464 Q462 R472 R473 Q463 R471 R470 R466 R467 R469 R468 Q462 C470 R416 75F 75F 75F 75F 37.4F 75F R436 C457 R419 C416 R415 R435 C455 R418 C415 R414 R434 C453 R413 R433 C451 R417 C414 R409 R412 R432 C449 C413 R408 C412 R431 R411 C447 R407 STBY 0 STBY 0 STBY 0 STBY 0 STBY 0 STBY 0 C411 R450 R452 R451 R448 R447 R449 VSEL1 SQUEEZE VSEL2 R_CR B_CB G_CY S_Y CVBS S_C GNDD 4.7k STBY 56k UMZ1N-TLB 1.2k 22k UMZ1N-TLB STBY 4.7k 0.1 UMZ1N-TLB 22k 560 DTA144EUA-TLB UMZ1N-TLB 56k V+5 820 10k 1.2k 1.2k GNDD 1k 0.1 STBY STBY GNDD STBY STBY STBY STBY STBY STBY V+10 STBY STBY STBY STBY 1-A6 A B 4/4 B 1/4 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com XV-DV232 25 5 6 7 8 5 6 7 8 C D F A B E SCART_R SCART_L TVOUT_R TVOUT_L H L V/Y R/C BLANK GND NC V/Y GND GND BLANK R/C GND L H G SQUEEZE B VIDEO AMP COMPOSITE GND GND NC G NC SQUEEZE L IN GND GND L OUT B R IN R OUT EURO CONNECTOR (2/2) (1/2) CCSR**~ CKSQ**~ CKSR**~ : 1608Size : 2125Size RS1/16S~ : 2125Size : 1608Size RS1/10S~ CAPACITOR Chip Size RESISTOR V OUTPUT VIDEO COMPOSITE 5 6 4 3 1 2 21 19 20 17 18 14 16 15 B 5 6 4 1 3 2 E C B C E 2 1 B C E 12 13 11 10 8 9 7 6 5 4 1 2 3 B2 C2 E E2 B C 1 2 R9421 R9423 C474 C476 D474 C473 C472 IC472 C475 D473 R478 C480 R477 R476 C492 C491 C490 R9402 R9407 Q9401 C9403R9406 R9401 R9404 R9403 C471 IC471 D472 D471 Q9402 R9408 C9404 C9401 D9401 R9410 R9411 R9405 C9402 Q491 R482 R9409 L9401 R491 Q492 R481 C479 C478 R475 C489 C488 C477 R474 C496 R496 C487 C493 C494 C486 C495 C482 R495 R484 R494 C485 R488 JA451 C484 R486 Q493 R483 Q493 R493 C483 C481 R485 R487 C427 R9412 C421 R421 JA403 STBY 0 0.1 GNDD 0.1 DAN202U 0.1 MM1507XN-TRB 0.1 V+5 0.1 DAP202U DAN202U GNDD STBY 1000/6.3 75 470/6.3 75 75 (F) STBY (F) (F) STBY 2SA1576 2.7k 100/6.3 220 1.8k 10/50 MM1505XN-TRB V+5 DAP202U 470 2SC4081 470 DTC124EUA-TLB GNDD GNDD V+5 68p STBY DAN217U 390 0.1 47/35 1k GNDD 390 390 STBY 390 V+10 LFEA680J-T DTA124EUA-TLB 10k 1k VE+5 470/6.3 0 0 STBY STBY 0.1 470/6.3 STBY 330 STBY STBY 100p CH 330 STBY 10/50 47k 4.7k CH 100p XKB3054- STBY 470 330p CH IMX9 IMX9 47k 4.7k 10/50 330p CH STBY 470 1000/6.3 GNDD STBY 10k (F) 75 VKB1122 3-C1 XTVMUTE 2-A2 3-C1 3-B1 3-B1 B 3/4 B 2/4 B 4/4 DVD MAIN ASSY (AWM7983:XV-DV232) (AWM8003:XV-DV240) (AWM7995:XV-DV535W) B 4/4 B 3/4 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com XV-DV232 26 1 2 3 4 1 2 3 4 C D F A B E 3.7 DAMP ASSY (1/2) LINE_OUT_L LINE_OUT_R LINE_IN_L LINE_IN_R XSD XOTW PCON + - + - XRST XRST SDA SCL LRCLK SDATA2 SDATA3 SDATA1 SCLK XMUTE SDA SCL MCLK DIGITAL AUDIO PWM PROCESSOR PWM_P_6 PWM_HPPL PWM_HPML PWM_HPPR PWM_P_5 PWM_M_6 PWM_HPMR PWM_M_5 XRST XPDN XHPSEL AND STBY STBY PCB Binder : VEF1040 C3182 R3181 IC3182 IC3181 C3181 R3182 CN3171 CN3102 R3155 R3154 R3908 R3912 C3908 C3904 C3902 C3912 R3924 IC3901 C3906 R3910 R3906 R3907 R3914 R3916 R3913 R3915 R3153 CN3101 C3152 C3151 R3151 R3152 C3922 C3924 R3911 C3921 C3923 C3907 C3903 C3911 C3901 R3923 R3921 IC3901 C3905 R3905 R3909 R3901 RESET CONTROL CIRCUIT GNDD RST 5V SDA SCL GND S_TVOUT_L GND GND RECMUTE S_TVOUT_R LIN1_R LIN1_L GND GND GND LRCLK SCLK MCLK GND SDATA3 SDATA2 SDATA1 GND GND XSD POWER GND XOTW GND SCL SDA GND XMUTE (2/2) XPDN XRST 3.3V GND GND HPR HPL XHPSEL PCON (1/2) 3 4 2 1 5 1 2 4 3 5 5 3 4 1 2 2 5 1 4 6 3 8 7 11 12 9 10 15 16 13 14 19 17 18 3 2 1 5 4 10 9 8 7 6 5 7 4 6 8 15 16 13 14 11 12 19 17 18 3 4 1 8 2 GNDD 4.7K 0.1/16 T-TPS3825-33DBVR SN74AHC1G04DBV-TLB 0.1/16 GNDD V+3R3 0 B5B-PH-K-S V+5V GNDD AKM7077- STBY STBY 18k 680p/50 5.6k 560p/50 680p/50 STBY NJM4565M 180p/50 10k 18k 5.6k 18k 5.6k 4.7k 4.7k 4.7k 4.7k 4.7k STBY AKM7077- STBY 0.1/16 10k 2.2k V+3R3 0.1/16 10/16 10/25 0.1/25 560p/50 680p/50 STBY 680p/50 10k 8.2 NJM4565M 180p/50 5.6k V+BSW 18k SCL SDA TAS5508 SDATA3 LRCLK SDATA1 SCLK SDATA2 XHPSEL XPDN XMUTE C3113 C3111 C3110 C3114 R3106 X3101 R3107 C3112 R3108 C3115 R3105 R3104 C3107 C3109 C3108 R3113 C3106 R3103 C3105 C3104 C3103 R3102 R3101 C3102 C3101 IC3101 R3112 C3120 C3119 DVSS RESERVED XTL_IN XTL_OUT SDA RESERVED RESERVED DVDD /MUTE /PDN /HP_SEL OSC_CAP VR_DPLL SCLK LCRCK SCL SDIN4 VR_DIG SDIN3 DVSS DVSS NC SDIN1 SIND2 /BKND_ERR DVDD /RESET VBGAP AVDD_PLL AVSS_PLL RESERVED PWM_HPPL PWM_HPMR PWM_HPPR VRD_PLL AVSS AVSS MCLK PWM_P_8 PWM_M_8 PWM_P_7 PWM_M_7 DVSS VALID PWM_M_1 PWM_P_1 PWM_M_2 PWM_P_2 PWM_M_3 PLL_FLTP PLL_FLTM PWM_M_6 PWM_P_6 PWM_HPML PLL_FLT_RET VRA_PLL DVDD_PWM PWM_P_5 PWM_M_5 DVSS_PWM PWM_P_3 PWM_M_4 VR_PWM PWM_P_4 16 15 14 13 12 11 10 18 17 20 19 21 23 24 22 27 26 25 28 29 30 33 31 32 35 34 37 36 8 9 7 6 40 43 42 39 41 38 5 4 3 2 1 63 64 61 62 60 59 58 57 45 44 46 47 48 56 54 55 51 53 52 50 49 GNDD 18p/50 10/10 0.1/16 STBY 1M 15p/50 ASS7062 47 0.1/16 47 0.1/16 V+3R3 220 GNDD GNDA 3.3 1000p/50 10/10 4.7 0.1/16 0.1/16 0.1/16 0.01/50 V+3R3 0.1/16 220 220 0.01/50 0.1/16 TAS5508APAG-TLB 47 0.1/16 10/10 3/4 CN 3002 B 3/4 CN 3001 B 2/2 C (AD) (AD) (AD) (AD) (AD) : VIDEO DATA SIGNAL ROUTE (AD) (AD) (AD) (AD) (AD) (AD) (AD) (AD) (AD) A C 1/2 HARD PHONE AMP www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com XV-DV232 27 5 6 7 8 5 6 7 8 C D F A B E XSD VALID PCON LINE_OUT_R PWM LINE_OUT_L LINE_IN_R LINE_IN_L from MAIN SMPS ASSY OUT COM IN + - + + - + - - XPDN PWM_P_1 PWM_M_2 PWM_M_1 PWM_P_2 PWM_M_4 PWM_M_3 PWM_P_3 PWM_P_4 PWM_P_8 PWM_P_7 PWM_M_8 PWM_M_7 PWM STBY Wireless only (AWK7876) Power Supply AKB7114 CN3111 Except WY/WV (AWK7874) 2125 size CKSQ** 1608 size CCSR** CKSR** capacitor 1608 size RS1/16S*** 2125 size RS1/10S*** 3216 size RS1/8S*** resistor C3117 C3116 C3172 C3171 IC3171 R3171 D3101 R3110 C3118 R3114 R3109 R3197 D3191 C3191 R3136 Q3132 R3134 R3196 Q3604 Q3901 R3133 R3132 D3131 R3131 Q3131 R3608 R3612 R3627 R3626 R3625 C3604 C3602 R3628 R3601 C3603 C3601 C3608 C3614 Q3602 R3606 IC3601 C3606 R3607 R3610 D3603 R3624 C3610 R3614 D3602 C3622 C3624 C3607 R3611 C3613 C3623 C3621 R3613 D3601 C3609 R3195 IC3191 C3192 CN3201 IC3191 R3194 R3193 R3192 R3199 R3198 R3191 R3616 Q3601 R3630 R3618 R3632 Q3603 R3620 C3612 R3631 Q3601 R3617 R3615 R3629 Q3603 C3611 R3619 R3605 IC3601 C3605 R3609 R3623 R3621 R3142 C3142 C3141 R3141 JA3111 VNF1084- KN3101 GND_CHASSIS (2/2) GND +B TVOUT_L TVOUT_R (1/2) TVIN_L TVIN_R 2 3 1 2 3 1 B C E B C E B C E B E C B 5 4 6 7 8 E C 3 1 4 1 8 3 4 2 2 1 5 4 7 8 6 B2 C2 E2 E B C 4 2 5 2 8 1 3 6 0.1/16 GNDD 10/10 GNDD 0.1/16 10/25 V+5V NJM78L05UA-TLB 330 GNDD 0 DAP202U 0.1/16 STBY V+3R3 UDZS4.7(B) 10K 10/25 10k DTC143EUA 2.2k 22 DTA124EUA 330p/50 STBY V+3R3 STBY 1k 12k 47k V+BSW 2SA1036K(QR) 4.7k 10K 330p/50 STBY STBY 330p/50 STBY STBY 4.7k 330p/50 330p/50 STBY DTA124EUA 10/16 4.7k HA17558AF 150p/50 4.7k 10K 10K 2.2k UDZS12(B) STBY 10/16 0.1/16 47k 330p/50 STBY * * 0.1/25 10/25 47k STBY 10/16 BA10358F GNDD B2P-VH 0.1/25 10K 100k 2.2k BA10358F 100k 10K 8.2 UDZS18(B) GNDD ACN7112 STBY V+B V+25 820 1k 220 4.7k IMX9 4.7k 4.7k IMX9 IMX9 820p/50 4.7k IMX9 1k 820 820p/50 220 4.7k HA17558AF 150p/50 10K 2.2k 8.2 V+BSW 330 220p/50 220p/50 RKB1041 330 R3111 DV535W only DV535W only EXCEPT DV535W DV535W only (AD) 2/2 C 2/2 C CN2 E C 1/2 D-AMP ASSY (AWK7874 : XV-DV232) (AWK7874 : XV-DV240) (AWK7876 : XV-DV535W) AUDIO OUT BUFFER POWER CONFID DETECT C 1/2 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com XV-DV232 28 1 2 3 4 1 2 3 4 C D F A B E 3.8 DAMP ASSY (2/2) PWM_P_2 PWM_M_2 PWM_P_4 PWM_M_4 PWM_P_1 PWM_M_1 PWM_P_3 PWM_M_3 XSD XOTW VALID XOTW XSD VALID PWM L3353 L3351 L3352 L3354 L3251 L3253 L3252 L3254 28 29 27 25 24 26 21 22 23 17 15 20 18 19 16 14 11 8 9 12 13 10 7 6 5 4 3 2 1 28 25 27 26 20 22 19 24 21 23 16 14 17 15 12 13 18 32 31 30 33 34 35 36 3 2 38 37 39 40 42 41 4 1 43 44 46 47 45 49 48 2 1 4 3 51 50 53 52 55 54 56 29 30 31 32 33 34 35 36 37 38 1 4 3 2 39 40 42 43 41 44 45 11 10 8 9 6 7 5 4 3 2 1 46 47 49 48 51 50 3 2 1 4 52 53 54 56 55 C3301 R3323 R3325 C3321 C3323 C3325 R3327 C3331 C3333 R3335 C3345 R3331 C3337 R3303 R3302 R3301 C3303 R3304 R3305 R3309 R3308 R3306 C3304 R3307 C3302 IC3301 R3201 C3201 R3202 R3203 R3204 C3203 R3205 R3209 R3315 C3311 C3341 R3341 C3327 R3311 C3315 C3335 R3343 C3343 C3313 R3317 R3313 C3317 L3301 R3316 C3342 C3312 R3344 R3342 C3316 R3312 C3334 R3333 C3339 R3337 C3347 R3336 R3332 C3346 C3344 C3314 R3318 C3318 R3314 C3328 C3332 L3302 R3326 R3324 R3328 C3326 C3324 C3336 R3225 C3221 R3223 C3223 C3225 C3338 R3334 C3340 R3338 C3348 R3215 R3227 C3227 C3231 C3233 C3211 C3241 R3241 R3243 R3211 C3215 C3235 C3243 C3213 R3216 R3217 R3213 C3217 C3216 L3201 R3235 C3245 R3231 C3237 R3233 C3239 R3237 C3247 C3204 R3207 R3208 C3202 R3206 IC3201 C3242 C3212 R3242 R3244 C3244 R3212 C3218 L3202 C3234 C3232 C3214 R3218 R3214 C3228 R3228 C3226 C3236 R3224 R3226 C3224 C3246 R3232 R3236 C3238 C3240 R3234 R3238 C3248 GNDD YB 1/16 V+BSW 820 820 1000/25 YB 0.01/50 1000p/50 3.3 YB V+B YB CFTLA474J50 0.1/25 1 STBY 4.7K 0.01/50 STBY STBY STBY 0.1/16 220 10K STBY YB 4.7K 100 YB 0.1/16 47K 1/16 YB TAS5122DCA-TBB GNDD STBY YB 1/16 V+BSW STBY STBY 220 0.1/16 10K STBY YB 0.1/50 330p/50 YB YB 1.5 0.033/50 0.1/25 2.7 YB YB 18 ATH7019 0.47/50 YB 330p/50 YB 0.1/50 18 0.033/50 2.7 YB 1.5 YB 10 YB 0.1/50 330p/50 YB YB 1.5 2.7 0.033/50 YB 18 18 10 ATH7019 YB 4.7K 0.01/50 0.1/25 1 YB STBY 0.1/25 1 STBY 330p/50 YB 0.1/50 2.7 0.033/50 0.1/25 YB YB 1.5 0.47/50 CFTLA474J50 YB 820 820 3.3 1000p/50 YB YB 0.01/50 YB V+BSW 820 820 V+B 0.01/50 1000/25 YB 1000p/50 4.7K 0.01/50 0.01/50 YB 4.7K 0.1/25 YB 1 STBY 0.1/50 3.3 YB V+B 1.5 2.7 0.033/50 0.1/25 YB CFTLA474J50 330p/50 YB YB YB 330p/50 0.1/50 YB YB 18 18 0.033/50 YB 0.47/50 10 ATH7019 YB YB 0.1/50 2.7 YB 1.5 1.5 2.7 0.033/50 0.1/25 1 STBY 4.7K 0.01/50 YB 4.7K 0.01/50 0.1/25 1 YB STBY 0.1/16 47K 4.7K 1/16 YB 100 YB TAS5122DCA-TBB 330p/50 YB YB 330p/50 YB 0.1/50 YB 18 18 2.7 0.033/50 0.1/25 10 ATH7019 YB CFTLA474J50 YB YB 1.5 3.3 1000p/50 0.47/50 YB V+BSW 820 820 YB YB 0.01/50 V+B STBY 0.1/25 4.7K 1 0.01/50 YB 0.01/50 0.1/25 4.7K YB 1 STBY GND GND GND GVDD GND OUT_D PVDD_D PVDD_D OUT_D DM DP GREG /SD_AB /SD_CD /OTW BST_D GND OUT_C OUT_C PVDD_C PVDD_C BST_C BST_B CM /RESET_CD M3 DREG_RTN CP M2 M1 GND GND OUT_B PVDD_B PVDD_B OUT_B AP BP DREG AM /RESET_AB BM DGND GND OUT_A OUT_A GND DVDD PVDD_A PVDD_A GREG GND GND GND BST_A GVDD BST_D PVDD_D /OTW GREG GND GND GVDD GND OUT_C PVDD_D OUT_D OUT_D CM /RESET_CD DM DP /SD_AB /SD_CD GND GND BP DREG M1 M2 M3 DREG_RTN CP OUT_C PVDD_C PVDD_C BST_C BST_B PVDD_B PVDD_B /RESET_AB BM OUT_B OUT_B AM AP GND GND DGND GND OUT_A OUT_A GREG DVDD GND BST_A PVDD_A PVDD_A GND GND GVDD GND 16 A C 2/2 C 2/1 C 1/2 AMP POWER STAGE AMP POWER STAGE 15 (FR) 15 16 16 16 (RL) 15 (RL) 15 (FR) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com XV-DV232 29 5 6 7 8 5 6 7 8 C D F A B E PWM_P_7 PWM_M_7 PWM_M_8 PWM_P_8 XSD XOTW VALID L3351 L3353 L3352 L3354 FR+ RR- RR+ FR- RL+ RL- FL+ FL- C+ SW- SW+ C- 28 29 27 26 25 24 23 22 21 31 32 30 34 33 36 35 17 15 16 20 19 18 38 37 40 39 42 41 14 12 13 10 11 8 9 44 43 45 46 47 49 48 4 3 2 6 5 7 51 50 53 52 55 54 1 56 3 2 4 1 4 3 2 1 2 1 3 4 5 8 6 7 12 10 11 9 C3401 R3423 R3425 C3421 C3423 C3425 R3427 C3433 R3435 C3431 R3431 C3437 C3445 R3402 R3401 R3403 R3404 C3403 R3405 R3409 C3441 R3415 C3427 C3411 R3411 C3415 R3441 C3443 R3443 C3413 R3413 C3417 R3417 C3442 R3416 C3416 C3412 R3412 R3444 R3442 C3404 R3406 R3408 R3407 C3444 C3418 C3414 R3414 C3428 R3418 IC3401 C3402 R3426 R3424 R3428 C3426 C3424 R3433 C3439 C3435 R3437 C3447 L3401 C3434 R3432 R3436 C3446 L3402 C3432 C3438 R3434 C3440 C3436 R3438 C3448 CN3211 GNDD YB 1/16 820 820 V+BSW YB 1000/25 0.01/50 3.3 YB V+B 1000p/50 0.1/25 1 CFTLA474J50 YB 4.7K 0.01/50 STBY STBY STBY STBY 220 0.1/16 10K STBY YB 330p/50 YB 0.1/50 1.5 0.033/50 YB 2.7 YB 18 YB 330p/50 18 0.033/50 YB 0.1/50 2.7 YB 1.5 330p/50 YB YB YB 0.1/50 1.5 2.7 0.033/50 YB 18 18 100 4.7K YB 0.1/16 47K 330p/50 YB 0.1/50 2.7 0.033/50 YB 1.5 TAS5122DCA-TBB YB 1/16 820 820 3.3 YB 0.01/50 YB V+BSW ATH7019 YB 0.1/25 YB 0.47/50 4.7K 0.01/50 0.1/25 1 YB STBY 10 YB 10 ATH7019 1 0.1/25 STBY YB 0.1/25 CFTLA474J50 YB 4.7K 0.01/50 YB 0.01/50 0.47/50 0.1/25 4.7K YB 1000p/50 YB 1 STBY V+B AKE7115- NOTICE R3211~R3214, R3311~R3314, R3411~R3414 : ACN7141-(2.7Ω) GND GND GND GVDD /OTW GREG /SD_AB /SD_CD DM DP BST_D PVDD_D PVDD_D OUT_D GND OUT_D M2 CM DREG_RTN M3 CP /RESET_CD M1 OUT_C GND PVDD_C OUT_C PVDD_C BST_C BST_B AP AM DREG BP /RESET_AB BM PVDD_B PVDD_B OUT_B OUT_B GND GND DVDD GREG GND DGND GND GND GND OUT_A OUT_A PVDD_A PVDD_A GVDD GND BST_A LAYOUT NOTE : L325X L335X L345X are PCB track inductors approx. 50mm long and 1mm wide C 2/2 C 2/2 D-AMP ASSY (AWK7874 : XV-DV232) (AWK7874 : XV-DV240) (AWK7876 : XV-DV535W) : AUDIO DATA SIGNAL ROUTE (Front Rch) (FR) : AUDIO DATA SIGNAL ROUTE (Rear Rch) (RR) : AUDIO DATA SIGNAL ROUTE (Front Lch) (FL) : AUDIO DATA SIGNAL ROUTE (Front Rch) (FR) : AUDIO DATA SIGNAL ROUTE (Sub woofer ch) (SW) : AUDIO DATA SIGNAL ROUTE (Center ch) (C) AMP POWER STAGE 15 (C) 15 16 16 (SW) C 1/2 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com XV-DV232 30 1 2 3 4 1 2 3 4 C D F A B E 3.9 FUNCTION ASSY SG1 SG2 SG3 SG4 SG7 SG6 SG5 SG9 SG8 SG11 SG10 SG15 SG12 SG13 SG14 GR1 GR4 GR2 GR3 VEE SG16 SG17 SG18 GR7 GR6 GR5 GR9 GR8 GR10 GR10 F- GR1 GR3 GR4 GR2 GR5 GR6 GR8 GR9 GR7 SG17 GR10 SG18 SG16 SG15 SG14 SG13 SG9 SG8 SG10 SG12 SG7 SG11 SG5 SG6 SG3 SG4 SG1 SG2 FL F+ Vout GND Vcc F- 10G 7G 6G 5G 3G 4G 1G 2G 9G P18 8G P17 P16 P15 P14 P13 P9 P10 P8 P7 P12 P11 P6 P5 P4 P3 P2 P1 F+ POWER ON VOL UP VOL DOWN HP FM/AM STOP /PAUSE PLAY OPEN/CLOSE KEY SR FL DRIVER FL KN5902 R5972 R5974 D5972 R5978 R5976 Q5973 Q5971 D5971 R5975 R5977 R5973 S5961 R5971 S5962 S5963 R5962 R5963 R5953 C5951 C5952 R5903 R5902 CN5901 R5990 R5982 R5980 R5984 R5986 C5972 R5988 L5972 C5974 Q5974 R5989 L5973 C5977 C5971 R5981 R5985 C5973 L5971 JA5901 R5979 R5983 S5964 S5965 S5966 R5987 S5967 R5964 R5965 R5966 R5952 R5954 R5951 KN5901 IC5902 C5920 C5921 C5922 C5915 R5901 R5904 IC5901 R5910 L5902 C5916 C5917 D5902 C5918 C5919 R5908 C5904 C5906 C5908 C5903 C5905 C5907 V5901 C5911 C5912 C5913 L5901 C5914 D5901 Q5901 R5905 R5909 R5906 Q5902 R5907 16 17 14 10 12 13 11 15 4 8 7 6 5 3 9 1 2 1 4 5 3 2 7 6 13 14 12 16 17 15 18 20 22 21 19 10 6 8 7 11 9 26 23 27 24 25 28 4 5 1 3 2 43 42 44 39 40 41 30 29 31 33 32 38 36 37 34 35 1 5 6 7 8 11 9 14 13 12 16 15 17 19 20 22 23 29 27 30 32 24 26 33 35 37 38 39 40 45 HP_R HPMUTE KEY1 GNDD From DVD ASSY HP_L GNDD HP_DET KEY2 GNDD VE+5 VFDP FLDC+ FLDC- REMOCON FLCS FLCK FLDATA VSS VDD VDD VSS VEE AAV7104- AEB7367 FL SPACER DISPLAY ASSY AWU8256 FL SPACER AEB7367 GNDD VNF1084 68 68 STBY 2.2k 2.2k IMX9-T DTA124EUA-TLB STBY 2.2k 2.2k 68 68 VSG1024 VSG1024 VSG1024 1k 47/6.3 0.022 JQ 52045-1745 STBY STBY 68 68 68 1000p 68 STBY 68 VTL1081- -T 0.047/25 IMX9-T STBY STBY 0.01/50 1000p 68 68 0.047/25 VTL1081- -T AKN7005-A 68 68 VSG1024 VSG1024 VSG1024 STBY VSG1024 1.2k 1.5k 1.8k 2.7k STBY STBY 100 47 VNF1084 GP1UM27XK0VF VFDP 220p 220p GNDD 220p 0.01/50 220 220 220 PT6315 82k 0 0.022/50 0.022/50 10 LCYA100J2520-T STBY 47/35 AL STBY STBY STBY STBY STBY AL 47/35 VE+5 0.022 0.022 AL 47/6.3 22 LCYA220J2520-T STBY STBY STBY STBY 0 STBY STBY STBY LCYA***J2520 RS1/16S***J ALL INDUCTORS ARE IN µH RS1/10S***J ALL RESISTORS ARE IN Ω AL : CEAL**M** AT : CEAT**M** CKSRYB**K50 UNLESS OTHERWISE SPECIFIED ALL CAPACITORS ARE IN µF JQ : CEJQ**M** NOTES FUNCTION ASSY (AWU8256) D D D CN5601 B 2/4 FUNCTION ASSY S5961 : POWER ON S5962 : VOL UP S5963 : VOL DOWN S5964 : FM/AM S5965 : STOP S5966 : PLAY/PAUSE S5967 : OPEN/CLOSE www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com XV-DV232 31 5 6 7 8 5 6 7 8 C D F A B E www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com XV-DV232 32 1 2 3 4 1 2 3 4 C D F A B E 3.10 POWER SUPPLY UNIT AC IN Ewww. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com XV-DV232 33 5 6 7 8 5 6 7 8 C D F A B E POWER SUPPLY UNIT (AWR7034) CN1001 B 2/4 CN3201 C 1/2 E E www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com XV-DV232 34 1 2 3 4 1 2 3 4 C D F A B E 3.11 WAVEFORMS Note : The encircled numbers denote measuring point in the schematic diagram. Measurement condition ; No. 1 to 10 : reference A1 (DVD), T2-chp 19, Color-bar No. 11 to 14 : reference A1 (DVD), T1 DVDM ASSY B 2 IC201-pin 39 [TROPENPWM] V: 1V/div. H: 5µsec/div. 3 IC201-pin37 [DMSO] V: 1V/div. H: 10µsec/div. V: 1V/div. H: 10µsec/div. V: 1V/div. H: 2sec/div. 1 IC201-pin47 [FG] V: 1V/div. H: 2msec/div. 8 IC401-pin23 [CompositeVideo Out] V: 1V/div. H: 10µsec/div. 4 CN102-pin 11, 10, 9 (IC101-pin 14, 13, 12) [SPINDLE (WVU)] V: 2V/div. H: 2msec/div. GND GND GND GND GND GND GND GND GND PLAY Tray : opening Pless OPEN key Pless PLAY key Braking a turn of disc [Tray stops] [TRAY OPEN] [DVD PLAY] [DMSO] [Tray is opening] [Tray is closing] 9 9 10 9 10 IC401-pin21 [S VIDEO OUT - Y] V: 1V/div. H: 10µsec/div. 10 IC401-pin26 [S VIDEO OUT - C] V: 1V/div. H: 10µsec/div. GND GND www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com XV-DV232 35 5 6 7 8 5 6 7 8 C D F A B E 11 IC201-pin215 [ACLK] V: 1V/div. H: 20nsec/div. 12 IC201-pin210 [ALRCK] V: 2V/div. H: 500nsec/div. 13 IC201-pin208 [ABCK] V: 2V/div. H: 500nsec/div. 14 IC201-pin209 [ASDATA0] V: 2V/div. H: 500sec/div. 15 IC3201, IC3301, IC3401 [PWM_M, PWM_P] V: 0.1V/div. H: 2µsec/div. 16 IC3201, IC3301, IC3401 [OUT_A, B, C, D] V: 0.5V/div. H: 2µsec/div. DAMP ASSY C GND GND GND GND GND GND 12 13 14 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com XV-DV232 36 1 2 3 4 1 2 3 4 C D F A B E www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com XV-DV232 37 5 6 7 8 5 6 7 8 C D F A B E 4. PCB CONNECTION DIAGRAM 4.1 LOAB ASSY NOTE FOR PCB DIAGRAMS : 1. Part numbers in PCB diagrams match those in the schematic diagrams. 2. A comparison between the main parts of PCB and schematic diagrams is shown below. 3. The parts mounted on this PCB include all necessary parts for several destinations. For further information for respective destinations, be sure to check with the schematic diagram. 4. View point of PCB diagrams. Symbol In PCB Diagrams Symbol In Schematic Diagrams Part Name B C E D D G G S S B C E B C E D G S B C E B C E B C E Transistor Transistor with resistor Field effect transistor Resistor array 3-terminal regulator Capacitor Connector P.C.Board Chip Part SIDE A SIDE B 1 5 5 1 SW2 (V+5D) V+3D LOAD- LOAD+ GND PNE-1B1 C102 C101 CN602 CN601 1 2 5 1 VWG2346- VWG2279- 5 VWG LOAB 5 1 VNP1836-C CN602 S101 CN601 SIDE A SIDE B LOAB ASSY A LOAB ASSY A CN103 B (VNP1836-C) (VNP1836-C) LOADING MOTOR ASSY M CN601 CN602 CN601 CN602 A A www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com XV-DV232 38 1 2 3 4 1 2 3 4 C D F A B E 4.2 DVD MAIN ASSY SIDE A DVD MAIN ASSY B B CN102 CN3 E CN1001 C CN601 A CN103 CN1 A CN101 To STEPPING MOTOR To SPINDLE MOTOR CN104 CN5901 D CN5601 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com XV-DV232 39 5 6 7 8 5 6 7 8 C D F A B E SIDE A (ANP7530-B) CN3101 C CN3001 CN3102 C CN3002 CN1 F CN5701 To CONNECT ASSY (CN5101) CN401 B Q305 Q304 Q1302 Q3005 Q1304 Q308 Q1401 Q1201 Q1410 Q801 Q821 Q428 Q3041 Q5703 Q3042 Q491 Q5701 Q463 Q462 Q3951 Q5525 Q461 Q4902 Q442 Q441 Q9401 IC401 IC472 IC5501 IC471 IC5503 IC5701 IC3004 IC201 IC203 IC5502 IC1101 IC3005 IC3003 IC101 IC3001 IC204 IC202 Q492 Q493 Q3031 Q3030 Q3032 Q307 Q1413 Q1202 Q1303 Q1301 Q3006 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com XV-DV232 40 1 2 3 4 1 2 3 4 C D F A B E SIDE B DVD MAIN ASSY B B CN3001 CN3002 CN5701 CN401 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com XV-DV232 41 5 6 7 8 5 6 7 8 C D F A B E SIDE B (ANP7530-B) CN102 CN1001 CN103 CN104 B CN5601 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com XV-DV232 42 1 2 3 4 1 2 3 4 C D F A B E 4.3 DAMP ASSY (ANP7531-C) CN3001 B CN3101 CN3002 B CN3102 CN2 E CN3201 SIDE A SIDE A DAMP ASSY C C C IC3191 IC3171 IC3401 IC3101 IC3301 IC3201 IC3181 IC3182 IC3901 IC3601 Q3131 Q3132 Q3604 Q3901 Q3603 Q3601 Q3602 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com XV-DV232 43 5 6 7 8 5 6 7 8 C D F A B E (ANP7531-C) CN3101 CN3102 CN3201 SIDE B SIDE B DAMP ASSY C C C www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com XV-DV232 44 1 2 3 4 1 2 3 4 C D F A B E 4.4 FUNCTION ASSY (ANP7532-B) CN5601 B CN5901 SIDE A SIDE A FUNCTION ASSY D D D IC5902 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com XV-DV232 45 5 6 7 8 5 6 7 8 C D F A B E (ANP7532-B) CN5901 SIDE B SIDE B FUNCTION ASSY D D D Q5901 Q5902 Q5973 Q5971 Q5974 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com XV-DV232 46 1 2 3 4 1 2 3 4 C D F A B E 4.5 POWER SUPPLY UNIT CN1001 B CN3 SIDE A SIDE A POWER SUPPLY UNIT E E E To AC POWER CORD CN1 CN3201 C CN2 Q51 Q1 IC101 IC201 IC405 IC403 IC451 IC452 Q301 Q601 Q501 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com XV-DV232 47 5 6 7 8 5 6 7 8 C D F A B E CN3 SIDE B SIDE B POWER SUPPLY UNIT E E E CN1 CN2 Q201 Q202 Q203 Q801 Q204 Q21 Q2 Q23 Q22 Q112 Q111 Q251 Q802 Q303 Q302 Q901 Q902 Q503 Q502 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com XV-DV232 48 1 2 3 4 1 2 3 4 C D F A B E 5. PCB PARTS LIST 7777 LIST OF HOLE PCB ASSEMBLIES 7777 CONTRAST OF PCB ASSEMBLIES AWM7983, AWM8003 and AWM7995 are constructed the same except for the following : AWK7874 and AWK7876 are constructed the same except for the following : Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List. The mark found on some component parts indicates the importance of the safety factor of the part. Therefore, when replacing, be sure to use parts of identical designation. When ordering resistors, first convert resistance values into code form as shown in the following examples. Ex.1 When there are 2 effective digits (any digit apart from 0), such as 560 ohm and 47k ohm (tolerance is shown by J=5%, and K=10%). Ex.2 When there are 3 effective digits (such as in high precision metal film resistors). 5 6 1 4 7 3 R 5 0 1 R 0 5 6 2 1 NOTES: 560 Ω 47k Ω 0.5 Ω 1 Ω RD1/4PU J RD1/4PU J RN2H K RS1P K 56 x 10 1 47 x 10 3 R50 1R0 561 473 5.62k Ω RN1/4PC F 562 x 10 1 5621 Mark Symbol and Description XV-DV232 /WYXJ XV-DV232 /WVXJ XV-DV240 /WYXJ XV-DV240 /WVXJ XV-DV535W /WYXJ XV-DV535W /WVXJ 1..LOAB ASSY VWG2346 VWG2346 VWG2346 VWG2346 VWG2346 VWG2346 1..DAMP ASSY AWK7874 AWK7874 AWK7874 AWK7874 AWK7876 AWK7876 1..DVD MAIN ASSY AWM7983 AWM7983 AWM8003 AWM8003 AWM7995 AWM7995 NSP 1..COMPLEX ASSY AWM7998 AWM7998 AWM7998 AWM7998 AWM7998 AWM7998 2..FUNCTION ASSY AWU8256 AWU8256 AWU8256 AWU8256 AWU8256 AWU8256 > 1..POWER SUPPLY UNIT AWR7034 AWR7034 AWR7034 AWR7034 AWR7034 AWR7034 1..FM/AM TUNER UNIT AXX7170 AXX7170 AXX7170 AXX7170 AXX7170 AXX7170 BDVD MAIN ASSY Mark Symbol and Description AWM7983 AWM8003 AWM7995 Q3006 Not used Not used DTC124EUA R3006 Not used Not used RS1/16S103J R5514 Not used RS1/16S473J RS1/16S473J R5516 RS1/16S473J Not used RS1/16S473J CDAMP ASSY Mark Symbol and Description AWK7874 AWK7876 D3603 Not used UDZS12(B) Q3601, Q3603 Not used IMX9 Q3602, Q3604 Not used DTA124EUA C3609, C3610 Not used CEVW100M16 C3611, C3612 Not used CCSRCH821J50 R3613, R3614 Not used RS1/16S473J R3615, R3616 Not used RS1/16S102J R3617, R3618, R3631, R3632 Not used RS1/16S472J R3619, R3620 Not used RS1/16S221J R3624 RS1/16S222J Not used R3629, R3630 Not used RS1/16S821J CN3111 Not used AKB7114 JA3111 RKB1041 Not used www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com XV-DV232 49 5 6 7 8 5 6 7 8 C D F A B E 7777 PCB PARTS LIST FOR XV-DV232/WYXJ UNLESS OTHER WISE NOTED Mark No. Description Part No. A LOAB ASSY OTHERS CN602 (CONNECTOR) S2B-PH-K-S CN601 (CONNECTOR) S5B-PH-K-S B DVD MAIN ASSY SEMICONDUCTORS IC3003 AK5357ET IC203 AYW7059 >IC1101 BA3948FP IC101 BD7995EFS IC5701 BU1924FS IC3001 HEF4052BT IC202 K4S641632H-TC75 IC471 MM1505XN IC472 MM1507XN IC201 MT1389FE/C2-L IC5501 PDC124B IC204 S-24CS04AFJ IC5503 S-93C46BD0I-J8T1 IC3005 TC74VHC157FTS1 IC3004 TC7WU04FU Q9401 2SA1576A >Q1202 2SB1689 Q1301 2SB1689 >Q1302 2SB1689 Q304, Q9402 2SC4081 Q492 DTA124EUA Q463 DTA144EUA Q1413, Q3951, Q491, Q801 DTC124EUA Q1201, Q1303, Q1304, Q5525 DTC143EUA Q1401, Q3005, Q307, Q308, Q821 HN1A01F Q5703 HN1C01FU Q493 IMX9 Q305 UM5K1N Q1410 UMD2N Q461, Q462 UMZ1N D1401, D1412, D852, D861 1SS355 D1402, D472, D474 DAN202U D9401 DAN217U D471, D473 DAP202U D1410 UDZS15(B) D1415, D801 UDZS4R7(B) COILS AND FILTERS L1501 LFEA220J L9401 LFEA680J L1305 VTL1095 CAPACITORS C252 CCSRCH100D50 C485, C486, C5701, C5703 CCSRCH101J50 C265 CCSRCH220J50 C227 CCSRCH221J50 C3057, C5714 CCSRCH270J50 C3056, C5712 CCSRCH330J50 C483, C484 CCSRCH331J50 C254 CCSRCH391J50 C5549 CCSRCH470J50 C211, C212 CCSRCH560J50 C5716 CCSRCH561J50 C9404 CCSRCH680J50 C251 CCSRCH9R0D50 C256, C3011, C3012, C3015, C3016 CEAT100M50 C3019, C3020, C3025, C3026, C3041 CEAT100M50 C3045, C471, C481, C482, C5524 CEAT100M50 C5719 CEAT100M50 C101, C1505, C5581 CEAT101M10 C3951, C3952 CEAT101M16 C373, C9403 CEAT101M6R3 C427, C480 CEAT102M6R3 C202, C237, C281, C291 CEAT221M6R3 C3043 CEAT2R2M50 C1103, C203, C206, C215 CEAT470M35 C3023, C3024, C309, C310, C5708 CEAT470M35 C5720, C9401 CEAT470M35 C201, C477–C479 CEAT471M6R3 C161, C230, C267, C296, C5502 CKSRYB102K50 C5604-C5608, C5707 CKSRYB102K50 C1501, C151–C153, C226, C3001 CKSRYB103K50 C3048, C5508, C5517-C5519 CKSRYB103K50 C5521, C5522, C5577, C5579, C5591 CKSRYB103K50 C5715 CKSRYB103K50 C131, C1502, C204, C205, C207 CKSRYB104K16 C209, C213, C214, C216, C217 CKSRYB104K16 C220, C222–C225, C228 CKSRYB104K16 C231–C236, C239–C241 CKSRYB104K16 C244–C246, C253, C257, C260 CKSRYB104K16 C266, C268, C271–C273, C282 CKSRYB104K16 C284–C288, C290, C3021, C3022 CKSRYB104K16 C3042, C3044, C3046, C3052, C3064 CKSRYB104K16 C371, C372, C374, C464, C470 CKSRYB104K16 C472–C476, C488, C5509, C5539 CKSRYB104K16 C5550, C5556, C5582, C9402 CKSRYB104K16 C102–C104 CKSRYB105K10 C1101, C1201, C121, C140, C243 CKSRYB105K6R3 C283, C289, C343–C347 CKSRYB105K6R3 C219 CKSRYB152K50 C144–C146, C208, C210 CKSRYB222K50 C269 CKSRYB333K16 C5713 CKSRYB472K50 C258, C259 CKSRYB473K25 C255 CKSRYB474K10 RESISTORS R5504, R5523, R5530, R5541, R5557 RAB4C221J R5561, R5570, R5573, R5584, R5592 RAB4C221J R225 RAB4C330J R474, R475 RS1/10S0R0J R491 RS1/10S103J R1202 RS1/10S121J R151, R153 RS1/10S1R0J R152, R154 RS1/10S1R8J R9403, R9404, R9409, R9410 RS1/10S391J R131–R136 RS1/10S4R7J Mark No. Description Part No. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com XV-DV232 50 1 2 3 4 1 2 3 4 C D F A B E R1302, R1304 RS1/10S561J R421, R476–R478 RS1/10S75R0F R1102-R1104 RS1/16S3302F R412 RS1/16S37R4F R279 RS1/16S5600F R411, R413–R416 RS1/16S75R0F Other Resistors RS1/16S###J OTHERS CN5701 (11P FFC CONNECTOR9 52045-1145 CN5601 (17P FFC CONNECTOR9 52045-1745 CN3001, CN3002 (19P RECEPTACLE) AKP7199 X5701 (CRYSTAL RESONATOR) ASS7004 X5501 (CRYSTAL RESONATOR) ASS7034 CN1001 (CONNECTOR B13B-PH-K-S CN103 (CONNECTOR) B5B-PH-K-S 0 (PCB BINDER) VEF1040 JA403 (1P JACK) VKB1122 CN104 (4P CONNECTOR) VKN1235 CN102 (12P CONNECTOR) VKN1243 CN101 (24P CONNECTOR) VKN1464 X3004 (12.288MHz) VSS1140 X201 (27MHz) VSS1168 JA451 (RGB CONNECTOR ) XKB3054 C DAMP ASSY SEMICONDUCTORS IC3191 BA10358F IC3601 HA17558AF IC3901 NJM4565M >IC3201, IC3301, IC3401 TAS5122DCA IC3101 TAS5508APAG Q3131 2SA1036K Q3132 DTC143EUA D3101 DAP202U D3131 UDZS18(B) D3191 UDZS4R7(B) COILS AND FILTERS L3201, L3202, L3301, L3302 ATH7019 L3401, L3402 ATH7019 CAPACITORS C3114 CCSRCH150J50 C3605, C3606 CCSRCH151J50 C3113 CCSRCH180J50 C3905, C3906 CCSRCH181J50 C3141, C3142 CCSRCH221J50 C3601-C3604, C3607, C3608 CCSRCH331J50 C3907, C3908 CCSRCH561J50 C3901-C3904 CCSRCH681J50 C3221, C3321, C3421 CEAT102M25 C3108, C3111, C3117, C3120 CEVW100M10 C3622, C3922 CEVW100M16 C3191, C3621, C3921 CEVW100M25 C3231, C3232, C3331, C3332 CFTLA474J50 C3431, C3432 CFTLA474J50 C3211-C3214, C3311-C3314 CKSQYB104K50 C3411-C3414 CKSQYB104K50 C3201, C3202, C3301, C3302 CKSQYB105K16 Mark No. Description Part No. C3401, C3402 CKSQYB105K16 C3109, C3225, C3226, C3325, C3326 CKSRYB102K50 C3425, C3426 CKSRYB102K50 C3102, C3105, C3223, C3224 CKSRYB103K50 C3237-C3240, C3323, C3324 CKSRYB103K50 C3337-C3340, C3423, C3424 CKSRYB103K50 C3437-C3440 CKSRYB103K50 C3101, C3103, C3104, C3106, C3107 CKSRYB104K16 C3110, C3112, C3115, C3116 CKSRYB104K16 C3118, C3119, C3151, C3203, C3204 CKSRYB104K16 C3303, C3304, C3403, C3404, C3624 CKSRYB104K16 C3924 CKSRYB104K16 C3192, C3227, C3228, C3233-C3236 CKSRYB104K25 C3327, C3328, C3333-C3336 CKSRYB104K25 C3427, C3428, C3433-C3436, C3623 CKSRYB104K25 C3923 CKSRYB104K25 C3241-C3244, C3341-C3344 CKSRYB331K50 C3441-C3444 CKSRYB331K50 C3215-C3218, C3315-C3318 CKSRYB333K50 C3415-C3418 CKSRYB333K50 RESISTORS R3191 (0.1 ohm/ 2W) ACN7112 >R3211-R3214, R3311-R3314 (2.7 ohm) ACN7141 >R3411-R3414 (2.7 ohm) ACN7141 R3151 RAB4C103J R3104 RAB4C221J R3152 RAB4C222J R3107, R3108 RAB4C470J R3601, R3901 RAB4C472J R3132 RS1/10S123J >R3241-R3244, R3341-R3344 RS1/10S180J >R3441-R3444 RS1/10S180J >R3227, R3228, R3327, R3328 RS1/10S3R3J >R3427, R3428 RS1/10S3R3J R3231-R3234, R3331-R3334 RS1/10S472J R3431-R3434 RS1/10S472J R3223-R3226, R3323-R3326 RS1/10S821J R3423-R3426 RS1/10S821J >R3235-R3238, R3335-R3338 RS1/16S1R0J >R3435-R3438 RS1/16S1R0J >R3199, R3621, R3921 RS1/16S8R2J R3215-R3218, R3315-R3318 RS1/8S1R5J R3415-R3418 RS1/8S1R5J Other Resistors RS1/16S###J OTHERS CN3211 (6CH SPEAKER JACK) AKE7115 CN3101, CN3102 (19P PLUG) AKM7077 X3101 (13.5MHz) ASS7062 CN320 (1 2P CONNECTOR) B2P-VH JA3111 (2P PIN JACK) RKB1041 0 PCB BINDER VEF1040 D FUNCTION ASSY SEMICONDUCTORS IC5901 PT6315 Q5971 DTA124EUA Q5973, Q5974 IMX9 Mark No. Description Part No. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com XV-DV232 51 5 6 7 8 5 6 7 8 C D F A B E COILS AND FILTERS L5902 LCYA100J2520 >L5901 LCYA220J2520 L5971, L5972 VTL1081 SWITCHES AND RELAYS S5961-S5967 VSG1024 CAPACITORS C5920-C5922 CCSRCH221J50 C5907, C5918 CEAL470M35 C5913 CEAL470M6R3 C5952 CEJQ470M6R3 C5971, C5972 CKSRYB102K50 C5915, C5977 CKSRYB103K50 C5911, C5912, C5916, C5917, C5951 CKSRYB223K50 C5973, C5974 CKSRYB473K25 RESISTORS R5971-R5974, R5979-R5982 RS1/10S680J Other Resistors RS1/16S###J OTHERS CN5901 (17P CONNECTOR9 52045-1745 V5901 (FL TUBE) AAV7104 5971 (FL SPACER ) AEB7367 JA5901 (MINITURE JACK) AKN7005 IC5902 (REMOTE RECIVER UNIT) GP1UM27XK0VF KN5901, KN5902 VNF1084 (WRAPPING TERMINAL) EPOWER SUPPLY UNIT This assembly has no service parts. FFM/AM TUNER UNIT This assembly has no service parts. Mark No. Description Part No. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com XV-DV232 52 1 2 3 4 1 2 3 4 C D F A B E 6. ADJUSTMENT 6.1 ADJUSTMENT ITEMS AND LOCATION 6.2 JIGS AND MEASURING INSTRUMENTS 1 2 Adjustment Items [Mechanism Part] [Electrical Part] Tangential and Radial Height Coarse Adjustment DVD Error Rate Adjustment Electrical adjustments are not required. Adjustment Points (Mechanism Part) Cautions: After adjustment, adjustment screw locks with the Screw tight. 1 2 Radial adjustment screw 1 2 Tangential adjustment screw Screwdriver (large) TV monitor Precise screwdriver DVD test disc (GGV1025) Test mode remote control unit (GGF1381) Screw tight (GYL1001) Screwdriver (medium) Soldering iron www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com XV-DV232 53 5 6 7 8 5 6 7 8 C D F A B E 6.3 NECESSARY ADJUSTMENT POINTS ∗ After adjustment, screw locks with the Screw tight. ~, Ÿ Mechanical point Electric point Mechanical point Electric point Mechanical point Electric point LOAB and DVDM ASSYS Exchange Parts of Mechanism Exchange PCB Assy When Adjustment Points Exchange the 05SD Pickup Assy Exchange the TM Assy VK1AVC Exchange PC Board www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com XV-DV232 54 1 2 3 4 1 2 3 4 C D F A B E 6.4 TEST MODE POWER ON DSC - &&& GGF1381 Test mode remote control unit GGF1381 Test mode remote control unit OPEN/CLOSE (Player) OPEN/CLOSE Press the play key ( ) of the normal remote control unit. (Player) TEST MODE: PLAY TEST MODE: OFF An address is displayed OR ESC ESC TEST CHECK DVD, CD DVD disc POWER ON OFF POWER DISC SET Notes: • After going into test mode, if you play back the disc, "DISC-NON" is displayed. • The video signal and the audio signal are outputted during the test mode. • The SKIP key and the SCAN key are effective during the test mode. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com XV-DV232 55 5 6 7 8 5 6 7 8 C D F A B E 6.5 MECHANISM ADJUSTMENT • Remove the 05SD Pickup Assy from the TM Assy VK1AVC. • Remove the joint and the joint spring of the 05SD Pickup Assy. • Put the joint between the Tangential (or Radial) adjustment screw and the mechanism base and turn each screw to adjust the height. (Refer to "6.1 ADJUSTMENT ITEMS AND LOCATION".) START Tangential and Radial Height Coarse Adjustment 1 Note: Before removing the flexible cable for the pickup, soldering of the pickup circuit is necessary. For details, see "7.1.11 DISASSEMBLY". • Pass through the guide shaft to a new 05SD Pickup Assy. • Attach it to the TM Assy VK1AVC. • Attach the TM Assy VK1AVC to the 05 LOADER Assy. • Turn it over and attach the joint and the joint spring. • Arrange the flexible cables. (Refer to "7.1.11 DISASSEMBLY".) 7.5mm Joint Mechanism base 05SD Pickup Assy 05SD Pickup Assy Joint Joint Spring Guide Shaft www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com XV-DV232 56 1 2 3 4 1 2 3 4 C D F A B E Player Monitor • Play the DVD test disc at inner track (around #30000) • Play the DVD test disc at outer track (around #200000) TM Assy VK1AVC Adjust the radial adjustment screw so that BER becomes around "5E-5". TM Assy VK1AVC Fasten the radial adjustment screw so that BER becomes around "1E-3". START DVD Error Rate Adjustment 2 BER : - - - - BER :around "5E-5" BER : around "1E-3" Service mode end Disc playback normally. • The measurement of block error rate If error rate is OK, locks a root of tangential and radial adjustment screws with the Screw tight. Screw tight: GYL1001 Turn the POWER OFF in case of NG once, and perform the adjustment once again. CHP/TIM ESC ESC \ Service mode Service mode end ESC NG OK • Play the DVD test disc at inner track • Display BER on the monitor CHP/TIM ESC Notes: • Use disc: GGV1025 • BER:Block Error Rate • Unfasten the radial adjustment screw by 90 degrees step till BER becomes around "1E-3" again . • Record the number of rotation (N1). (memorizing how much the screw was rotated.) • Fasten the radial adjustment screw till the number of rotation becomes harf of N1. TM Assy VK1AVC Fasten the tangential adjustment screw so that BER becomes around "1E-3". • Unfasten the tangential screw by 90 degrees step till BER becomes around "1E-3" again . • Record the number of rotation (N1). • Fasten the tangential adjustment screw till the number of rotation becomes harf of N1. BER : around "1E-3" Confirm that the error rate is under "5E-5". CHECK CHP/TIM ESC www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com XV-DV232 57 5 6 7 8 5 6 7 8 C D F A B E 7. GENERAL INFORMATION 7.1 DIAGNOSIS 7.1.1 TEST MODE Test Mode Functional Specification 1 Test mode entry In the power ON state, press the [ESC] (A8-5F) key and [TEST / RANDOM] (A8-5E) key in order of the Test mode remote control unit. • OSD displays test mode. 2 LD ON Enter the test mode. DVD : Press the [TEST] (A8-5E) and [1] (A8-01) keys in order, and turn on the laser diode (650n). CD : Press the [TEST] (A8-5E) and [4] (A8-04) keys in order, and turn on the laser diode (780n). 3 Release the Test mode • Turn off the power. • Press the [ESC] (A8-5F) key of the remote control unit and reset it. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com XV-DV232 58 1 2 3 4 1 2 3 4 C D F A B E 7.1.2 DISPLAY SPECIFICATION OF THE TEST MODE Character in bold : Item name : Information display 1 5 6 10 11 8 9 3 2 12 15 13 14 1 Address indication The address being traced is displayed in number. (as for the DVD, indication of decimal number is possible.) DVD : ID indication (hexadecimal number, 8 digits) [∗ ∗ ∗ ∗ ∗ ∗ ∗ ∗] CD : ID indication [∗ ∗ ∗ ∗ ∗ ∗ ∗ ∗] 2 Code indication of remote control unit [R – ∗ ∗ ∗ ∗] In case of double code, display a 2nd code. 3 Main unit keycode indication [K – ∗ ∗] 5 Tracking status [TRKG – ∗ ∗ ∗] Tracking on : [ON] Tracking off : [OFF] 6 Spindle status [SPDL – ∗ ∗ ∗] CLV : [CLV] Off : [OFF] 7 Mechanism (loading) position value [M – ∗ ∗] Unknown : [01] or [41] Open state : [04] Close state : [08] During opening : [12] During closing : [22] 8 Slider position [S – ∗ ∗ ∗ ∗] In Side Switch ON : [01] In Side Switch OFF : [00] 9 Output video system [V – ∗ ∗ ∗ ∗] NTSC system : [NTSC] PAL system : [PAL] Automatic setting : [AUTO] Scart terminal output [SK – ∗ ∗] (Display only the WY model which can do the output setting of scart terminal.) VIDEO : [00] S-VIDEO : [01] RGB : [02] 0 Disc sensing [DSC – ∗ ∗ ∗] The type of discs loaded is displayed. [DVD], [CD ] - Jitter value [J – ∗ ∗ ∗ ∗] Note: Don't use it. = Version of the FL controller [FL: ∗ ∗ ∗ ∗] Note: Don't use it. ~ Region setting of the player [REG: ∗] Setting value : [1] to [6] ! Destination setting of the FL controller [MDL: ∗ ∗ ∗ ∗ / ∗ ∗ ∗] Four characters in the front represent code 01. Three characters in the back represent the destination code. J: /J, K: /KU, /KC, /KU/KC, R: /RL/RD, RAM : /RAM, LB: /LB, WY: /WY @ Version of the flash ROM [V: ∗ ∗. ∗ ∗] Flash ROM size [FLASH = ∗ ∗] 7 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com XV-DV232 59 5 6 7 8 5 6 7 8 C D F A B E 7.1.3 FUNCTIONAL SPECIFICATION OF THE SHORTCUT KEY • Service mode indication (ESC + CHP/TIM keys) ID Address The error rate is always displayed in exponential notation, e.g., ∗.∗ ∗ e - ∗, for both DVDs and CDs. EDC/ID/AV 1 error history (ID Address, EDC/ID Error, last eight errors) • Calculation of the average error rate (ESC + "5" [Test mode remote control unit] keys) The average of the last eight error rates is calculated and indicated in exponential notation. After the calculation is completed, "OK" or "NG" is displayed. If "NG" is displayed, the disc tray will open (for both DVDs and CDs) For DVDs: OK with 5.0e-4 or less, for CDs: OK with 7.6e-3 or less • Indication of model information (ESC + CHAP keys) The items from 12 to 15 of the TEST MODE Indications are displayed. However, in the indications, S in the standard test mode is changed to CHIP VERSION, and M is changed to RF VERSION. For details, see 7.1.4. • Region confirmation mode (ESC + A.MON [Test mode remote control unit] + "1"-"8" [Test mode remote control unit] keys) After you press the AUDIO key while holding the ESC key pressed and then input the region number, if the number is different from that set in the unit, an error message is displayed, and the tray opens. Command Contents Conditions Remote Control Key Name Remote Control Code Memory clear and region / revision indication CLEAR (∗1) A8-45 Average value measurement of DVD error rate 5 (∗1) A8-05 CD error rate measurement 5 (∗1) A8-05 Scart terminal output : VIDEO WY, models equipped with Scart terminal AUDIO A3-BE Scart terminal output : S-VIDEO SUBTITLE A3-36 Scart terminal output : RGB ANGLE A3-B5 Progressive OFF Only for progressive models R_SKIP A3-9D Progressive ON F_SKIP A3-9C FL indication of ID number STEREO (∗1) A8-4A ZOOM ON (×4) ZOOM A3-37 Service mode indication (error rate indication, etc.) CHP/TIM (∗1) A8-13 Model information indication CHAP (∗1) A8-40 Title search Input mode IN Title No. input Search execution SIDE A (∗1) Numbers (∗1) PLAY (∗1) A8-4D A8-00 to A8-09 A8-17 Region confimation mode A.MON (∗1) Numbers (∗1) A8-1E A8-01 to A8-08 Only during normal playback, the following shortcut keys can be assigned by pressing a required key after pressing the ESC key of the remote control unit. To quit, press the ESC key ∗1 : Test mode remote control unit www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com XV-DV232 60 1 2 3 4 1 2 3 4 C D F A B E 7.1.4 SPECIFICATION OF MODEL INFORMATION DISPLAY • Display contents Character in bold : Item name : Information display 1 2 3 4 5 6 7 9 10 1 Destination indication Display it according to model information set from the FL controller. 2 Region No. 3 Part number 4 ROM version 5 Flash size 6 FL controller version 7 CHIP VERSION 9 Remote control code 0 Key code of Main unit To display model information : Press the ESC key then the CHAP key. To close the model information display : Press the ESC key. Don't care. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com XV-DV232 61 5 6 7 8 5 6 7 8 C D F A B E 7.1.5 FUNCTIONAL SPECIFICATION OF THE SERVICE MODE • Display during Service Mode To enter Service Mode, press the CHP/TIM key while holding the ESC key pressed. To quit, press the ESC key. Service mode display 1 ID Address 2 Error rate (always displayed), in exponential notation ERROR RATE : ∗ ∗ ∗ ∗ ∗ ∗ ∗ ( ∗ ∗ ∗ ∗ ) • Calculation of the average error rate For DVDs: OK with 5.0e-4 or less, for CDs: OK with 7.6e-3 or less 3 EDC/ID error history (ID Address, EDC/ID errors, last eight errors) Note: ∗ Error of AV1 is not supported in this player. Number of error Indication plan contents Character in bold : Item name : Information display 1 2 3 ex) For DVDs • Step 1 %%e -& %%e -6 : OK %%e -5 : OK %%e -4 : Refer to Step 2 %%e -3 : NG %%e -2 : NG • Step 2 %%e -4 3.0e -4 : OK 4.0e -4 : OK 5.0e -4 : OK 6.0e -4 : NG 7.0e -4 : NG www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com XV-DV232 62 1 2 3 4 1 2 3 4 C D F A B E 7.1.6 SERVICE TEST MODE 1. Conditions During Service Test Mode • During Service Test mode, the unit will not be shut down for an emergency even if one of the failures mentioned below occurs. • After the unit has been shut down in Normal mode for an emergency upon detection of one of the failures mentioned below, you can turn it on immediately, without waiting for one minute, in Service Test mode. • The accumulated power-on time can be checked during Service Test mode. 2. How to enter Service Test mode • Connect AC power cord with the STEST port (microcomputer terminal IC5501: 43-pin) at High (5 V). (See "Service Test mode connecting point".) Note: Initial function setting is DVD/CD. • Connect AC power cord while holding both the OPEN/CLOSE and POWER keys on the main unit pressed. The unit will be turned on, and the following indication will be displayed: 3. How to quit Service Test mode, and conditions for quitting • To quit Service Test mode, turn the power off or disconnect the AC power cord to turn the power off. • When Service Test mode is quit, only data on protection in RAM will be initialized, and data on user settings in RAM will not be initialized. 4. Indications on the FL display when Service Test mode is entered • Indications on the FL display when Service Test mode is entered differ depending on whether the unit was turned off normally or shut down for emergency protection, immediately before Service Test mode starts, as follows: 5. Operations during Service Test Mode • Basically, operations in Service Test mode are the same as in Normal mode. However, to indicate that the unit is in Service Test mode, the following are displayed when the functions are changed: W e l c o m e [After a normal power-off] [After a shutdown caused by an EEPROM (IC5503) failure] FL display V o l 0 V o l 0 FL display V D D V S E R V D D V S E R FL display E E P E R R FL display V o l 0 FL display V D D V S E R V o l 0 V D D V S E R FL display P R T C T E FL display FL display FL display V D S E R DVD/CD T X S E R TUNER N 1 S E R LINE1 O V E R P T E M FL display FL display FL display [After a shutdown caused by an AMP-system failure] [After a shutdown caused by high-temperature detection] V o l 0 V D D V S E R V o l 0 V D D V S E R D V D P R T C T FL display FL display FL display O C E R R R O FL display FL display FL display [After a shutdown caused by a DVD-system failure] [After a shutdown caused by over current detection] [Functions] [FL display] N 2 S E R LINE2 L N V V V V V D L L S E R LINE (for Europe model) (for Europe model) (for North America, general model) When the function is set to LINE2 (Europe model) or LINE (Except Europe model), the Surround setting is fixed to 5-channel STEREO, which is only for Service Test mode. (In Normal mode, it is fixed to 2-channel STEREO.) In such a case, do not check the sound through the headphones, because headphone operation with 5-channel STEREO is not guaranteed. If you wish to check the sound through the headphones, use a function other than LINE2 (Europe model) or LINE (Except Europe model). • www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com XV-DV232 63 5 6 7 8 5 6 7 8 C D F A B E 6. Failures • Depending on the types of errors, one of the following error messages will be displayed when the unit is turned on: E E P E R R P R T C T E D V D P R T C T Version of the system-controller About 3 seconds after O C E R R R O A protection circuit was activated: 1. The V+10, V+5, V+3R3, or VFDP was short-circuited (See the protection circuit on "3.4 DVD MAIN ASSY (2/4)"), or the value at V+10, V+5, or V+3R3 exceeded the standard value because of an abnormality in its power section. 2. The XPROTECT line up to the system-control computer (PDC124B) was short-circuited by grounding or was broken. 7. Accumulated power-on time display • Hold the STOP key on the unit pressed for 8 seconds during Service Test mode. After the version for the system-control computer is displayed, the accumulated power-on time is displayed. P D C 1 2 4 B Accumulated power-on time 1 0 H 3 0 M • Power-on time is always counted while the power is on, regardless of unit's functions and operations. However, it is not counted during Standby mode. • The maximum countable power-on time is 255H59M (255 hours 59 minutes.) The indication will not advance beyond that. • The accumulated power-on time basically cannot be cleared. Abnormality in the DVD section 1. The V+6R8, V+5V, or V+3 was short-circuited, or the value at V+6R8, V+5V, or V+3 exceeded the standard value because of an abnormality in its power section. 2. The VDET line up to the system-control computer (PDC124B) was short-circuited by grounding or was broken. (See VDET circuit on "3.4 DVD MAIN ASSY (2/4)") • If "OC ERROR" is not displayed when the unit is turned on in Normal mode, short-circuiting of the speaker terminals can be suspected. (It causes speaker cable "+", "-" short.) • If "OC ERROR" is displayed again when the unit is turned on in Normal mode, the following causes can be suspected: 1. One or more of the ICs among the three digital amplifier ICs (IC3201, IC3301, and IC3401: TAS5122DCA) on the W51 DAMP Assy is in failure. 2. The line between one of the above digital amplifier ICs and the speaker terminals is short-circuited. 3. The XSD line from one of the above digital amplifier ICs to the system-control computer (PDC124B) is short-circuited by grounding or is broken. O V E R P T E M • If "OVERTEMP" is not displayed when the unit is turned on in Normal mode, the unit is normal. The protection circuit was activated because the temperature at the three digital amplifier ICs (IC3201, IC3301, and IC3401: TAS5122DCA) had become too high. Because it is likely that this was a temporary temperature rise, lower the volume of the speakers. • If "OVERTEMP" is displayed again when the unit is turned on in Normal mode, the following causes can be suspected: 1. One or more of the ICs among the three digital amplifier ICs (IC3201, IC3301, and IC3401: TAS5122DCA) on the W51 DAMP Assy is in failure. 2. The XOTW line from one of the above digital amplifier ICs to the system-control computer (PDC124B) is short -circuited by grounding or is broken. 1. Breakage or short-circuiting of the communication line between the µ-COM (IC5501) and the EEPROM (IC5503) can be suspected. 2. A failure in the EEPROM (IC5503) can be suspected. Service Test Mode connecting point DVD MAIN ASSY B Connecting point SIDE A www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com XV-DV232 64 1 2 3 4 1 2 3 4 C D F A B E How to release the Tray Lock Reference information Problem Press the � OPEN/CLOSE key. The "TRAYLOCK" indication flashes. Remedy Hold the � OPEN/CLOSE key pressed for 8 seconds or more until "LOCK Off" is displayed. Then the tray can be opened/closed, using the � OPEN/CLOSE key. How to lock the tray 1. Make sure the disc is clamped (in Disc Stop mode). 2. Hold the � OPEN/CLOSE key pressed for about 8 seconds. (Hold the key pressed even if the tray opens.) 3. The "LOCK?" indication flashes on the FL display. 4. Within 3 seconds after "LOCK?" begins flashing (while it is flashing), release the key, then hold the � OPEN/CLOSE key pressed again. (If you don't perform this step, the tray will not be locked, and the indication will return to the normal display.) 5. After the key has been held pressed for about 5 seconds, the "LOCK ON" indication appears on the FL display. Once it does, release the key. (If you keep the key pressed, the Tray Lock will be released again.) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com XV-DV232 65 5 6 7 8 5 6 7 8 C D F A B E 7.1.7 METHOD FOR DIAGNOSING DEGRADATION OF THE LDs ON THE PICKUP ASSY Case when this diagnosis is required : When playback of any disc, including a test disc (DVD: GGV1025, CD: STD-905), won't play or doesn't play How to diagnose In the case mentioned above, degradation of the laser diodes (LDs) mounted on the 05SD Pickup Assy is suspected. Measure the voltage between the two ends of one of the resistors mentioned below. Measure the voltage between the both ends of R322 or R325 on the DVDM Assy. If the voltage is 0.4 V or higher, the 650-nm LD is degraded. No playback of a DVD : Measure the voltage between the both ends of R321 or R326 on the DVDM Assy. If the voltage is 0.4 V or higher, the 780-nm LD is degraded. No playback of a CD : If the measurements show degradation of an LD, replace the 05SD Pickup Assy. DVD MAIN ASSY B SIDE A Front side PICKUP ASSY CN101 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com XV-DV232 66 1 2 3 4 1 2 3 4 C D F A B E 7.1.8 DVD TROUBLE SHOOTING No. Symptoms Diagnosis Contents Possible Defective Points 1 The power is not turned on. Are wires of output connector (POWER SUPPLY Unit) and CN1001 (W51 DVDMAIN Assy) disconnected or damaged ? Connector / cable Check that the following voltage is output : Q1202-collector on the W51 DVDMAIN Assy: 3.3V POWER SUPPLY Unit 2 An opening screen is not displayed on the monitor (The FL display lights. The mechanism does not work.) Are the signals output from IC201-pin 98 (MDATA) and pin 99 (SCLK) on the W51 DVDMAIN Assy ? (in the range of 0-3V) W51 DVDMAIN Assy DVD IC (IC201) Are the signals input into IC5501-pin 50 (MDATA) and pin 51 (SCLK) on the W51 DVDMAIN Assy ? (in the range of 0-3V) W51 DVDMAIN Assy UCOM (IC5501) Check that the following voltage are output : Q1302-collector on the W51 DVDMAIN Assy: 5V W51 DVDMAIN Assy 5V Regulator IC (IC751) Is a resonator (X201: 27MHz) on the W51 DVDMAIN Assy oscillating ? W51 DVDMAIN Assy Crystal resonator (X201) DVD IC (IC201) • Is a signal input into IC203-pin26 (PCE#) on the W51 DVDMAIN Assy ? (Is a signal "H" for 80 mS and then "L" after the power is turned on ?) → Communication with flash ROM. • Are the signals input into IC202-pin 16 (DWE#), pin 19 (DCS#) and pin 38 (SDCLK) on the W51 DVDMAIN Assy ? (Is a signal fluctuating ?) → Communication with SDRAM W51 DVDMAIN Assy DVD IC (IC201) Flash ROM (IC203) SDRAM (IC202) Is a signal output from IC203-pin 28 (PRD#) on the W51 DVDMAIN Assy? (Is a signal fluctuating for several hundred mS after the power is turned on ?) W51 DVDMAIN Assy Flash ROM (IC203) Is a signal input into IC5501-pin 67 (DVD ACK) on the W51 DVDMAIN Assy ? (Is a signal fluctuating ?) → Communication with FL Control IC W51 DVDMAIN Assy DVD IC (IC201) UCOM (IC5501) Is a signal output from IC5501-pin 30 (XREADY) on the W51 DVD MAIN Assy ? (Is a signal fluctuating in the range of 0-5V ?) W51 DVDMAIN Assy UCOM (IC5501) Are the signals output from IC5501-pin 23 (SDATA) on the W51 DVD MAIN Assy ? (in the range of 0-5V) W51 DVDMAIN Assy DVD IC (IC201) UCOM (IC5501) Are the signals of IC204-pin 5(SDA) and pin 6(SCL) on the W51 DVD MAIN Assy fluctuating for one or two seconds after the power is turned? W51 DVDMAIN Assy EEPROM (IC204) 3 An opening screen is not displayed on the monitor (The FL display lights. The mechanism works.) Check the video signal path between DVD IC (W51 DVDMAIN Assy IC201) and video-out terminal (see the block diagram) W51 DVDMAIN Assy Video circuit after DVD IC (IC201) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com XV-DV232 67 5 6 7 8 5 6 7 8 C D F A B E No. Symptoms Diagnosis Contents Possible Defective Points 4 A tray cannot be opened. (An opening screen is displayed on the monitor) Does the voltage of CN104-pin 3 and pin 5 on the W51 DVDMAIN Assy change normally ? Pin 3 (SW2(TRIN)): Tray is fully closed: "L" Pin 5 (SW1(TROUT)): Tray is fully opened: "L" LOAB Assy Tray SW (S101) Is the signal input into IC101-pin 11 (TROPEN) on the W51 DVDMAIN Assy? At open: 3.3V, At close: 0V W51 DVDMAIN Assy DVD IC (IC201) Are the signals output from IC101-pin 1 and pin 2 (CN103-pin 1 and pin 2) on the W51 DVDMAIN Assy ? Pin 2: Approx. 6V during opening tray approx. 0V during closing tray. Pin 1: Approx. 0V during opening tray approx. 6V during closing tray. W51 DVDMAIN Assy FTS Driver IC (IC101) Are wires of CN104 and CN103 on the W51 DVDMAIN Assy disconnected or damaged ? Connector / cable Does the voltage of CN102-pin 1 on the W51 DVDMAIN Assy change to 0V by pressing the Inside switch. Inside switch 5 Playback impossible (no focusing) Are the signals output from IC101-pin 3 (FOCS_DRV) and pin 4 (FOCS_RTN) on the W51 DVDMAIN Assy ? W51 DVDMAIN Assy FTS Driver IC (IC101) Does 650-nm LD emit light ? Does a pickup lens move up / down ? Does an actuator spring bend ? Pickup Are plastic parts damaged ? Or is a shaft detached ? Is the turntable detached or tilted ? Mechanism section (motor) Is flexible cable of CN101 on the W51 DVDMAIN Assy disconnected or damaged ? Flexible cable / connector Is signal output from IC201-pin 42 (FOSO) on the W51 DVDMAIN Assy ? (Device control of about 1.4 V is output usually. It is fluctuated by about ± 250 mV with focus up / down.) W51 DVDMAIN Assy DVD IC (IC201) 6 Playback impossible (Spindle does not turn) Are the signals output from IC101-pin 30 (W), pin 33 (V) and pin 35 (U) on the W51 DVDMAIN Assy ? Is pin 26 (STBY) fixed LOW ? (pin 26 is High at playback: 3V) W51 DVDMAIN Assy FTS Driver IC (IC101) Is there any part detached from the spindle motor ? Or Is there any foreign object lodged in it ? Mechanism section (Spindle motor) Are wires of CN102 on the W51 DVDMAIN Assy disconnected or damaged ? Flexible cable / connector Is signal output from IC201-pin 37 (DMSO) on the W51 DVDMAIN Assy ? W51 DVDMAIN Assy DVD IC (IC201) 7 Playback impossible (Playback stops) Does 650-nm LD deteriorate ? If the voltage at each both ends of R322 and R325 on the W51 DVD MAIN Assy is 0.4 V or more, the 650-nm LD is definitely deteriorated. 650-nm LD deteriorated. (When playback of a DVD is impossible) Does 780-nm LD deteriorate ? If the voltage at each both ends of R321 and R326 on the W51 DVD MAIN Assy is 0.4 V or more, the 780-nm LD is definitely deteriorated. 780-nm LD deteriorated. (When playback of a CD is impossible) Is there abnormality in FG waveform ? (IC201-pin 47) W51 DVDMAIN Assy FG output : FTS Driver IC (IC101) Are there scratches or dirt on the disc ? Disc 8 Picture disturbance during playback (block noise, freeze, other) Are there scratches or dirt on the disc ? Is there a problem with the format of the disc ? Check the video signals. Composite video signal (IC401-pin 25) S video signal (IC401-pin 21, pin 26) RGB video signal (IC401-pin 16, pin 18, pin 20) Disc 9 No sound (Picture is normal) Check the waveform (SPDIF: CN901-pin 16). W51 DVDMAIN Assy DVD IC (IC201) W51 DVDMAIN Assy DVD IC (IC201) Video IC (IC401, IC451) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com XV-DV232 68 1 2 3 4 1 2 3 4 C D F A B E Symptoms that may occur when any of the following ICs is in failure IC Symptoms EEP ROM (W51 DVDMAIN Assy : IC204) User's data cannot be stored in memory. The ID number is lost. Flash ROM (W51 DVDMAIN Assy : IC203) The power cannot be turned on. Downloading of the firmware cannot be performed. DVD IC (W51 DVDMAIN Assy : IC201) Any kind of symptoms (no power, a failure in any of the servo, video and audio systems, etc.) may be generated, because the DVD processing is performed by a single chip. 64M SDRAM (W51 DVDMAIN Assy : IC202) No power. Block noise is generated during playback. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com XV-DV232 69 5 6 7 8 5 6 7 8 C D F A B E 7.1.9 ID NUMBER AND ID DATA SETTING This display appears when the PLAY key is pressed in Step 4. Enter a 9-digit number to compare. The number is also displayed on the FL display. 6 By pressing the CLEAR key without having input a number, the unit returns to Step 2 without doing anything else. Each press of this key after a number has been input deletes one digit. 7 After entering all 9 digits, if you press the PLAY key, the unit compares the numbers input in Steps 2 and 6, and only if the numbers match, that number is set as the ID. Then the unit automatically enters ID DATA Input Mode. If the numbers do not match, the disc tray is opened, and the unit exits ID Number Input Mode. 8 [Player's ID Number Setting] ID Number ? 0 0 0 0 0 0 0 0 1 Compare ∗ ∗ ∗ ∗ ∗ ∗ ∗ ∗ ∗ Input ID Number ! 6 [Player's ID Number Setting] ID Number ? 0 0 0 0 0 0 0 0 1 Compare 0 0 0 0 0 0 0 0 1 Enter Input ID Number ! 8 Input ID Number ! After entering all 9 digits, if you press the SEARCH key, the unit unconditionally sets the input number as the ID number. Then the unit automatically enters Player's Data Input Mode. (The SEARCH key is not accepted after all 9 digits have been entered.) 5 [Player's ID Number Setting] ID Number ? 0 0 0 0 0 0 0 0 1 Compare Mode

Enter 4 5 Caution: For the DVD players compatible with DVD-RW, for playback of a DVD-RW disc (CPRM), it is necessary that an individual ID number and ID data are set for each player. If the ID number and ID data be not properly set in the manner described below, future operations cannot be guaranteed. The ID number is written on the yellow label at the rear panel of the player. If there is no yellow label, before downloading FLASH ROM, take note of the ID number set following the procedures outlined in "ID Number Confirmation Mode" on the next page. Note: Enter ID numbers while the unit is in Stop mode so that the values set will be immediately written to the flash ROM. Note: If you press the PLAY button before inputting a 9-digit ID number, the unit returns to Step 6 without doing anything else. To enter ID Number Input Mode, with no ID number set, such as in a case of immediately after upgrading the firmware, press the ESC key then the STEREO key. Note: If a previous ID number and ID data, such as a factory- preset ID number and ID data, are maintained, the unit enters ID Number Confirmation Mode when the above keys are pressed. However, if only an ID number is maintained, the unit enters ID Data Input Mode. ID Number Input Mode [Player's ID Number Setting] ID Number ? - - - - - - - - - Exit Input ID Number ! 1 Enter a 9-digit ID number. The ID number is also displayed on the FL display. 2 By pressing the CLEAR key without having input a number, you can exit this mode. Each press of this key after a number has been input deletes one digit. 3 After entering all 9 digits, if you press the PLAY key, the unit enters Compare mode. Enter the same ID number again. Only if your two input numbers match, the ID number is set. Compare mode helps eliminate mistyping of the ID number. 4 2 3 Note: If you press the PLAY button before inputting a 9-digit ID number, the unit returns to Step 2 without doing anything else. Setting an ID number or ID data is required in the following case: If "No NUM" or "NO DATA" is displayed on the FL display for a few seconds immediately after the power to the player is turned on or during Stop mode. JIGS AND MEASURING INSTRUMENTS DVD Data Disc [GGV1175] Service Remote Control Unit [GGF1381] www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com XV-DV232 70 1 2 3 4 1 2 3 4 C D F A B E To enter ID Number Confirmation Mode after the ID number and the ID data are set, press the ESC key then the STEREO key. ID Number Confirmation Mode 1 The ID number already set is displayed. (It is also displayed on the FL display.) 2 Enter a 9-digit number for comparison. This is not required when you only wish to check the ID number visually. (The number is also displayed on the FL display.) 3 By pressing the CLEAR key without having input a number, you can exit this mode. Each press of this key after a number has been input deletes one digit. 4 After entering all 9 digits, if you press the PLAY key, the unit compares the number entered in Step 2 with the ID number set, and only if the numbers match, the unit automatically exits ID Number Confirmation Mode. If an ID data has not been entered, the unit enters ID DATA Input Mode. If the numbers do not match, the disc tray is opened, and the unit exits ID Number Confirmation Mode. 5 After entering all 9 digits, if you press the STOP key, the unit compares the number entered in Step 3 with the ID number set, and only if the numbers match, the unit automatically deletes the ID number and exits this mode. If the numbers do not match, the disc tray is opened, and the unit exits this mode. (The STOP key is not accepted after all 9 digits have been entered.) 6 [Player's ID Number Setting] ID Number ? 0 0 0 0 0 0 0 0 1 Compare ∗ ∗ ∗ ∗ ∗ ∗ ∗ ∗ ∗ Exit Input ID Number ! 3 2 4 [Player's ID Number Setting] ID Number ? 0 0 0 0 0 0 0 0 1 Compare 0 0 0 0 0 0 0 0 1 Enter Memory Clear Input ID Number ! 5 6 Note: If you press the PLAY button before inputting a 9-digit ID number, the unit returns to Step 4 without doing anything else. • Indication of an ID number already set An ID number already set is displayed in the following cases: 1) When the ESC key then the CLEAR key are pressed, user settings are cleared, then the ID number set is displayed on the screen. In this case, the ID number is not displayed on the FL display. 2) When the unit enters ID Number Confirmation Mode by your pressing the ESC key then the CLEAR key, the ID number set is displayed. In this case, the ID number is also displayed on the FL display. If you only need to confirm the ID number, you can exit this mode by pressing the CLEAR key or turning off the power. • Indication when no ID number is set If no ID number is set, the message "No NUM" flashes on the screen and FL display for a few seconds after the power is turned on or during Stop mode. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com XV-DV232 71 5 6 7 8 5 6 7 8 C D F A B E To enter ID DATA Input Mode, with the ID number set, press the ESC key then the STEREO key. ID DATA Input Mode 1 When writing of the data read from the disc to flash ROM is completed, "Rom Write OK!" is displayed. After seeing this message, you can exit this mode by pressing the CLEAR key. 5 If the data cannot be read from the disc, "Disc Error!" is displayed on the screen, and the disc is ejected. 6 When the STEREO key is pressed, the unit enters ID DATA Input Mode. 2 If the DVD DATA DISC is loaded in this mode, the unit automatically starts reading the data. (If the DVD DATA DISC has already been loaded, the unit does not start reading the data. In this case, open then close the tray.) 3 To exit this mode, press the CLEAR key. While data are being read from the DVD DATA DISC, you cannot exit this mode. 4 [Player's ID Number Setting] ID Number ? [ 0 0 0 0 0 0 0 0 1 ] Compare > ∗ ∗ ∗ ∗ ∗ ∗ ∗ ∗ ∗ Exit ID Data Setting Mode Input ID Number ! 2 [Player's Data Input Mode] Exit Insert The ID Data Disc ! 4 [Player's Data Input Mode] Rom Write OK! Exit 5 [Player's Data Input Mode] Disc Error! Exit 6 Note: Whether or not the data have been written to flash ROM can be confirmed by watching for the message "Rom Write OK!" being displayed after the disc is read. • Indication when the data have not been set If no ID data are set after the ID number is changed, the message "NO DATA" flashes on the screen and FL display for a few seconds after the power is turned on or during Stop mode. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com XV-DV232 72 1 2 3 4 1 2 3 4 C D F A B E 7.1.10 POWER ON SEQUENCE KEY input Canceling muting • The time required to cancel muting varies depending on the acoustic-field setting. It takes longer to cancel muting if SFC or the channel level has been set. • When the function is set to DVD, the time required to cancel muting differs depending on a DVD operation. Muting continues until disc detection has been finished. PWRCNT2 (P84) SYSTEM STANDBY → ON 0msec 300 600 900 1200 1500 1800 2100 2400 2700 3000 3300 3600 5-10sec XHPMUTE (P31) XRECMUTE (P32) XTVMUTE (P95) DATASEL (P34) ADPDN (P76) INPUTSELB (P74) INPUTSELA (P75) XDAPDN (P71) D-AMP XDARST (P70) XDAMUTE (P72) DASDA/DASCK (P27/P28) DVDPOWER (P1) DVD XDVDRST (P96) SDATA/MDATA/SCLK/XREADY /DVDACK (P23/P24/P25/P67/P30) TXCE/TXCLK/TXIDATA (P52/P61/P66) TUNER RDSPOW (P64) FLCS/FLCLK/FLDAT (P58/P59/P60) DISPLAY Communication start Communication start Communication start For a European model, level is Low only at the power on and the function is FM. Communication start (Communication is possible first more than RWRCNT2 because power supply of a FL driver is the same as a microcomputer.) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com XV-DV232 73 5 6 7 8 5 6 7 8 C D F A B E 7.1.11 CIRCUIT DESCRIPTION OF DIGITAL AMP. SECTION AC IN AUDIO IN R L OUT R L WIRELESS LINE 2 SPEAKERS R L R L SUB WOOFER CENTER FRONT SURROUND Filter and Volume Timing Control Gate Drive XSD To UCOM PCM Signal From DVD or ADC 3.3V 0V TAS5508APAG PWM Processor section PWM Processor section Power Stage section Power Stage section Output LPF section Output LPF section TAS5122DCA XOTW Protection PCM → PWM Gate Drive 20V 0V 0V 0V The PCM signals output from the DVD decoder or AD converter are input to this section, and their volume and sound quality are digitally adjusted. At the output stage, after conversion from PCM to PWM, the signals are output to the Power stage. In this section, timing is controlled so that the MOSFETs on the high and low sides will not be turned on simultaneously. The voltage of the PWM signals are raised to drive the gates of the MOSFET, and the PWM signals to drive the speakers are output from the MOSFET at the output stage. Detection and protection functions against short-circuiting of the output signals and temperature exceeding the standard value are also provided. The carrier elements, high-frequency signals that are unnecessary for these speakers, are eliminated. The signals passed through the LPF will become sine-wave signals, as shown in the figure above. Attention As a signal to drive the BTL is output from the negative speaker terminal, DO NOT short-circuit between the negative speaker terminal and ground, such as the chassis. Negative Speaker Terminal Ground (Chassis) Do not short-circuit www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com XV-DV232 74 1 2 3 4 1 2 3 4 C D F A B E 7.1.12 DISASSEMBLY 1 Remove the bonnet case by removing the nine screws. 2 Press the � STANDBY/ON button to turn on the power. 3 Press the 0 OPEN/CLOSE button to open the tray. 4 Remove the tray cap Assy. 5 Set the test disc. 6 Press the 0 OPEN/CLOSE button to close the tray. (Test disc is clamped.) 7 Press the � STANDBY/ON button to turn off the power. 8 Pull out the Power cord. Bonnet Case, Tray Cap Assy 1 3 6 5 4 Tray cap Assy Screwdriver (small) Screwdriver (small) 05 LOADER Assy Tray open Slit Test disc Tray How to open the tray when the power cannot be on Insert a screwdriver (small) into the slit located at the bottom of the unit, and slide the projection of the drive cam in the 05 LOADER Assy in the direction of the arrow, as indicated in the photo. If the tray pops out a little, fully pull it out by hand. Diagnosis of PCB's Note 1: Do NOT look directly into the pickup lens. The laser beam may cause eye injury. Note 2: Even if the unit shown in the photos and illustrations in this manual may differ from your product, the procedures described here are common. 7 2 Drive cam Projection 6 3 Bottom view www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com XV-DV232 75 5 6 7 8 5 6 7 8 C D F A B E 1 Remove the eight hooks. 2 Remove the front panel section. Front panel section 2 Front panel section 2 1 1 ×2 Rear view 04 LOADER Assy 2 2 2 2 3 3 4 1 Short-circuit point by soldering. 2 Disconnect the four connectors. Note: After replacement, connect the flexible cable, then remove the soldered joint (open). 3 Remove the two screws. 4 Remove the 05 LOADER Assy. 1 1 ×2 1 05SD Pickup Assy Removing the TM Assy VK1AVC and 05SD Pickup Assy 05 LOADER Assy 1 1 1 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com XV-DV232 76 1 2 3 4 1 2 3 4 C D F A B E 1 Remove the one screw. 2 Remove the bridge 04. 3 Pull out the tray, then remove it by pressing the hook. 1 2 3 Bridge 04 Front side Hook Tray Loading base Triangle Pin Drive cam -2 3 -2 Note when reinserting the tray When reinserting the tray, first align the triangle printed on the loading base and the pin of the drive cam, then insert the tray. Bridge 04, Tray 2 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com XV-DV232 77 5 6 7 8 5 6 7 8 C D F A B E 1 TM Assy VK1AVC 3 Dislodge the two flexible cables from their factory placement. 2 Unhook the four hooks. 3 Remove the TM Assy VK1AVC. × 2 2 × 2 2 3 TM Assy VK1AVC 1 1 Front Side Flexible cable for the spindle motor Flexible cable for the pickup Bottom view www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com XV-DV232 78 1 2 3 4 1 2 3 4 C D F A B E 3 2 2 Adjustment screw (skew screw VK1) Adjustment screw (skew screw VK1) Adjustment screw (skew screw VK1) Adjustment spring (skew spring VK1) 05SD Pickup Assy 4 Note: The 05SD Pickup Assy can be removed without removing the TM Assy VK1AVC. (shown as Step π.) Note: Be careful not to lose the adjustment spring (skew spring VK1). Flexible cable for the pickup 05SD Pickup Assy 1 Front Side 1 Disconnect the flexible cable for the pickup. 2 Remove the two adjustment screws. 3 Remove the 05SD Pickup Assy. Bottom view 05SD Pickup Assy www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com XV-DV232 79 5 6 7 8 5 6 7 8 C D F A B E Note: The screw is secured with the silicone adhesive. Make sure to apply the silicone adhesive after reattaching the screw. 4 Remove the one screw. 4 Silicone Adhesive GEM1037 05SD Pickup Assy Joint VK1B Joint spring VK1 : Conductive surface Arrangement of the flexible cable for the spindle motor Front Side Hook Hook Bottom view www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com XV-DV232 80 1 2 3 4 1 2 3 4 C D F A B E Front Side Note: Be sure to move the 05SD Pickup Assy to the innermost perimeter. : Conductive surface Arrangement of the flexible cable for the pickup 2 3 7 2 Attach the flexible cable for the pickup to the connector. 6 Fold the flexible cable along the hook. 7 Pass the flexible cable through the hook. 3 Pass the flexible cable through the hook. Bottom View Make sure that the cable is loose Backing Backing Reference line Hook Hook 4 5 5 Pass the flexible cable through the hook. 4 Hook the part folded in Step 1 to the hook. Hook Reference line 6 Hook 1 Fold the flexible cable for the pickup with the backing outward in the illustration below. 76 mm 1 Hook Hook www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com XV-DV232 81 5 6 7 8 5 6 7 8 C D F A B E 7.2 PARTS 7.2.1 IC PDC124B (W51 DVDMAIN ASSY : IC5501) • System Control Microcomputer Pin Functions • The information shown in the list is basic information and may not correspond exactly to that shown in the schematic diagrams. • List of IC PDC124B, BD7995EFS, MT1389FE/C2-L, TAS5122DCA, AK5357ET, TAS5508APAG, PT6315, BU1924FS, S-93C46BD01-J8T1 No. Mark Pin Name I/O Pin Function 1 PA3/WR# DVDPOWER O Control power supply for DVD module 2 PA4/RD# HPDET I Detect to insert headphone 3 PA5/RS HPSEL O TAS5508 HP_SEL 4 P70 / INT0 / T0LCP / AN8 ACDET I Powerdown Detection 5 P71 / INT1 / T0HCP / AN9 P_ON I REMOCON 2 ( Power On ) 6 P72 / INT2 / T0IN RDSCLK I(O) Clock input from RDS decoder (Interruption 2, without RDS : Low output) 7 P73 / INT3 / T0IN REMOCON I REMOCON signal input (Interruption 3) 8 RES# XRESET I µ-com reset input 9 XT1 / AN10 XT1 − Subclock (connect to VDD when no use) 10 XT2 / AN11 XT2 − Subclock (leave open when no use, and set the bit 6 of OCR SFR) 11 VSS1 VSS1 − 12 CF1 CF1 − Main Clock (connect to VDD when no use) 13 CF2 CF2 − Main Clock (leave open when no use) 14 VDD1 VDD1 − 15 P80 / AN0 SIMUKE I Destination distinction input 16 P81 / AN1 MODEL I Model distinction input 17 P82 / AN2 VDET I DVD3.3V detection input Ground Power supply − − Ground Power supply 18 P83 / AN3 I 19 P84 / AN4 KEY2 I(O) Key2 input 20 P85 / AN5 I(O) 21 P86 / AN6 PCONFIG I Power Configuration 22 P87 / AN7 XPROTECT I Protection and Fan Error detection input 23 P10/SO0 SDATA O System bus data output (AMP side output) 24 P11 / SI0 / SB0 MDATA I System bus data input (AMP side input) 25 P12 / SCK0 SCLK I System bus clock input 26 P13 / SO1 O 27 P14 / SI1 / SB1 DASDA I(O) I2C data for D-AMP 28 P15 / SCK1 DASCL O I2C clock for D-AMP 29 P16/T1PWML O 30 P17/T1PWMH/BUZ XREADY O XREADY for DVD module 31 PE0 XHPMUTE O HP MUTE ON/OFF 32 PE1 XRECMUTE O REC OUTPUT MUTE ON/OFF 33 PE2 (UTEST_CHK) O UNITCHECK IN for checker 34 PE3 SELPOW O Data Selector 35 PE4 (UTEST_EEPOK) O EEPROM CHECK OK for checker 36 PE5 (UTEST_MODE) O CHECK MODE of UNITECHECK for checker 37 PE6 O 38 PE7 O 39 VSS4 VSS4 40 VDD4 VDD4 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com XV-DV232 82 1 2 3 4 1 2 3 4 C D F A B E No. Mark Pin Name I/O Pin Function 41 PF0 O 42 PF1 O 43 PF2 STEST I Set TESTMODE for Service 44 PF3 UTEST I Set UNITCHECK for checker 45 PF4 O 46 PF5 O 47 PF6 O 48 PF7 EEP_CS O 49 SI2P0/SO2 EEP_DO O 50 SI2P1/SI2/SB2 EEP_DI I 51 SI2P2/SCK2 EEP_SK O 52 SI2P3/SCK20 TXCE O Chip enable for tuner LSI 53 PWM1 O 54 PWM0 O 55 VDD2 VDD2 56 VSS2 VSS2 57 P00 O Reset for FL driver 58 P01 FLCS O Chip enable for FL driver 59 P02 FLCLK O Clock for FL driver 60 P03 FLDAT O Data for FL driver (serial data input) 61 P04 TXCLK O Clock for tuner LSI 62 P05 TXODAT O Data for tuner LSI 63 P06 O 64 P07 RDSPOW O Control power supply of RDS(L: POWER ON) 65 P20/INT4/T1IN RDSDATA I(O) Input RDS data 66 P21/INT4/T1IN TXIDATA I Input data from tuner LSI 67 P22/INT4/T1IN DVDACK I Ackknowlegement from DVD MODULE(Interruption 4) 68 P23/INT4/T1IN O 69 P24/INT5/T1IN KEY1 I Key1 input ( PowerOn/Standby key only) 70 P25/INT5/T1IN XDARST O RESET for D-AMP 71 P26/INT5/T1IN XDAPDN O POWER DOWN for D-AMP 72 P27/INT5/T1IN XDAMUTE O D-AMP MUTE 73 P30 O 74 P31 INPUTSELB O AUDIO INPUT SELECT B 75 P32 INPUTSELA O AUDIO INPUT SELECT A 76 P33 ADPDN O POWER DOWN for A/D 77 P34 SHUTDWN I D-AMP SHUTDOWN detection 78 P35 I 79 P36 XOTW I D-AMP Over Temperature Warning 80 PB7/D7 O − − Ground Power supply www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com XV-DV232 83 5 6 7 8 5 6 7 8 C D F A B E • Port0 (P00-P07) can be selected for input or output by each 4 bits (P00-P03,P04-P07). Set for input when reset. And it can be set C-MOS or Nch-OD by each 1 bit in option. • Port1 (P10-P17) can be selected for input or output by each 1 bit. Set for input when reset. And it can be set C-MOS or Nch-OD by each 1bit in option. • Port2 (P20-P27) can be selected for input or output by each 1 bit. Set for input when reset. And it can be set C-MOS or Nch-OD by each 1 bit in option. • Port3 (P30-P36) can be selected for input or output by each 1 bit. Set for input when reset. And it can be set C-MOS or Nch-OD by each 1 bit in option. • Port7 (P70-P73) can be selected for input or output by each 1 bit. Set for input when reset. • Port8 (P80-P87) can be selected for input or output by each 1 bit. Set for input when reset. • PortA (PA0-PA5) can be selected for input or output by each 1 bit. Set for input when reset. And it can be set C-MOS or Nch-OD by each 1 bit in option. • PortB (PB0-PB7) can be selected for input or output by each 1 bit. Set for input when reset. And it can be set C-MOS or Nch-OD by each 1 bit in option. • PortC (PC0-PC7) can be selected for input or output by each 1 bit. Set for input when reset. And it can be set C-MOS or Nch-OD by each 1 bit in option. • PortE and PortF can be selected for input or output by each 2 bits. • In case of without RDS, it is best that RDSDATA and RDSCLK are assigned as I/O port which can be set output and output low level. No. Mark Pin Name I/O Pin Function 81 PB6/D6 O 82 PB5/D5 I 83 PB4/D4 O 84 PB3/D3 PWRCONT2 O Power control for SMPS 85 PB2/D2 O 86 PB1/D1 O 87 PB0/D0 O 88 VSS3 VSS3 − 89 VDD3 VDD3 − 90 PC7/A7 FLASHE/D − for FLASH writing / On board debugger 91 PC6/A6 FLASHDO − for FLASH writing / On board debugger 92 PC5/A5 FLASHCLK − for FLASH writing / On board debugger 93 PC4/A4 O 94 PC3/A3 TXPOWER O Control power supply of Tuner etc. 95 PC2/A2 XTVMUTE O Control mute of SCART(Audio) 96 PC1/A1 XDVDRST O RESET to DVD MODULE 97 PC0/A0 O 98 PA0/CS2# O 99 PA1/CS1# O 100 PA2/CS0# O Ground Power supply www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com XV-DV232 84 1 2 3 4 1 2 3 4 C D F A B E • Video Driver 47kΩ 94kΩ 1 LDO+ 2 LDO- 3 FCO+ 4 FCO- 5 TKO+ 6 TKO- 7 AVM 8 AGND 9 TKIN 10 FCIN 11 LDIN 12 DVCC 13 SLVDD 14 SLRNF2 15 SLRNF1 16 SLGND 17 SLO1+ 18 SLO1- 19 SLO2+ 20 SLO2- 21 SLIN2 22 44 43 42 41 40 39 38 37 36 35 34 33 32 31 30 29 28 27 26 25 24 23 SLIN1 VCC HU+ HU- HV+ HV- HW+ HW- HB SPGND1 U SPVM1 V SPGND2 SPVM2 W SPRNF FG CTL1 CTL2 SPIN DGND VC BD7995EFS (W51 DVDMAIN ASSY : IC101) Block Diagram Pin Function LEVEL SHIFT No. Pin Name I/O Pin Function No. Pin Name I/O Pin Function 1 LDO+ O Loading driver positive output 23 VC I Control reference voltage input 2 LDO- O Loading driver negative output 24 DGND − Pre-ground for PWM block 3 FCO+ O Focus driver positive output 25 SPIN I Spindle control input 4 FCO- O Focus driver negative output 26 CTL2 I Driver logic control input 2 5 TKO+ O Tracking driver positive output 27 CTL1 I Driver logic control input 1 6 TKO- O Tracking driver negative output 28 FG O FG signal output 7 AVM − Actuater driver power supply 29 SPRNF I Spindle current detecting input 8 AGND − Ground for BTL block 30 W O Spindle W-phase output 9 TKIN I Tracking driver input 31 SPVM2 I Power supply input 2 of spindle block 10 FCIN I Focus driver input 32 SPGND2 − Power ground 2 of spindle block 11 LDIN I Loading input 33 V O Spindle V-phase output 12 DVCC − Control power supply for PWM block 34 SPVM1 I Power supply input 1 of spindle block 13 SLVDD − Pre-power supply for Sled motor MOS 35 U O Spindle U-phase output 14 SLRNF2 I Current detection input of sled motor driver 2 36 SPGND1 − Power ground 1 of spindle block 15 SLRNF1 I Current detection input of sled motor driver 1 37 HB − Hall bias 16 SLGND − Ground of sled motor driver power 38 HW- I Hall signal W- input 17 SLO1+ I Positive output of sled motor driver 1 39 HW+ I Hall signal W+ input 18 SLO1- O Negative output of sled motor driver 1 40 HV- I Hall signal V- input 19 SLO2+ O Positive output of sled motor driver 2 41 HV+ I Hall signal V+ input 20 SLO2- O Negative output of sled motor driver 2 42 HU- I Hall signal U- input 21 SLIN2 I Sled motor driver input 2 43 HU+ I Hall signal U+ input 22 SLIN1 I Sled motor driver input 1 44 VCC − Pre loading power supply for BTL block LEVEL SHIFT PRE LOGIC STBY/ BRAKE CONTROL 3-phase MATRIX PRE LOGIC LIMIT FF LEVEL SHIFT 47kΩ 47kΩ FF OSC 15kΩ 15kΩ 47kΩ 47kΩ 47kΩ 94kΩ 47kΩ 94kΩ LIMIT FF OSC PWM OUT Current LIMIT HALL BIAS FG REVERSE DETECT TSD FG COMP Polarity Current COMP www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com XV-DV232 85 5 6 7 8 5 6 7 8 C D F A B E MT1389FE/C2-L (W51 DVDMAIN ASSY : IC201) • DVD IC 1 OSN 2 3 4 DVDRFIP 5 DVDRFIN 6 MA 7 MB 8 MC 9 MD 10 11 SB 12 SC 13 SD 14 CDFON 15 CDFOP 16 TNI 17 TPI 18 MDI1 19 MDI2 20 LDO2 21 LDO1 22 V2REFO 23 VREFO 24 V20 25 TEO 26 FEO 27 28 29 HRFZC 30 CRTPLP 31 RFRPDC 32 RFRPAC 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60 61 62 63 64 256 IREF 255 RFGC 254 253 RFLVL / RFON 252 251 250 249 248 247 246 245 244 243 242 241 240 239 238 237 236 235 234 233 232 231 230 229 228 227 226 225 224 223 222 221 220 219 218 217 216 215 214 213 212 211 210 209 208 207 206 205 204 203 202 201 200 199 198 197 196 195 194 193 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80 81 82 83 84 85 86 87 88 89 90 91 92 93 94 95 96 97 98 99 100 101 102 103 104 105 106 107 108 109 110 111 112 113 114 115 116 117 118 119 120 121 122 123 124 125 126 127 128 129 130 131 132 133 134 135 136 137 138 139 140 141 142 143 144 145 146 147 148 149 150 151 152 153 154 155 156 157 158 159 160 161 162 163 164 165 166 167 168 169 170 171 172 173 174 175 176 177 178 179 180 181 182 183 184 185 186 187 188 189 190 191 192 SA DVSS IOA1 IOA0 IOA3 IOA4 IOA2 DMO FG / V_ADIN8 FMO IOA5 IOA6 IOA7 APLLVSS DVDD3 DVDD3 AD3 AD1 AD0 AD2 HIGHA0 HIGHA3 HIGHA1 HIGHA2 HIGHA5 AD6 AD5 AD7 AD4 HIGHA4 HIGHA6 HIGHA7 A16 A17 IOA18 IOA19 IOA20 DVDD3 UP3_5 IOOE# INT0# UP1_7 UP3_4 UP3_0 RD4 RD6 RD3 RD2 RD1 RD0 RWE# CAS# RAS# RCS# RD14 RD13 RD12 BA0 RD15 RD10 RD9 RD11 RD7 DVSS DVSS DVDD18 IOCS# IOWR# UP1_2 UP1_3 UP1_4 UP1_5 UP1_6 UP3_1 URD# IR UWR# ALE RD8 APLLVDD3 CKE RA11 RCLK DVSS RA9 RA8 TRO FOO LPFIN PLLVDD3 JITFN JITFO LPFOP PLLVSS CEQP LPFIP LPFON TROPENPWM PWMOUT1 / V_ADIN9 YUV4/G YUV6/R YUV7 PRST# DVSS DVDD18 SPBCK DACVSSB DACVDDA DACVDDB DACVDDC HSYN / V_ADIN2 VSYN / V_ADIN1 USB_VDD3 ICE XTALI XTALO YUV2/C YUV1/Y YUV3/CVBS SPLRCK SPDATA SPMCLK DACVSSA YUV5/B ADCVSS ADCVDD3 RA4 RA7 RA6 RA5 RD26 DQM1 RA0 DQM0 RD30 RA10 RA1 RA2 RA3 RD31 DVDD18 RD29 NC NC NC RD25 RD24 DQM2 NC NC DQM3 NC NC NC DVDD18 ABCK NC ASDATA2 ASDATA1 DVSS ALRCK ASDATA0 ACLK DVDD3 VREF DACVSSC FS YUV0/CIN ASDATA3 ASDATA4 SPDIF MC_DATA BA1 DQS0 DQS1 NC NC DVDD3 DVSS NC RD5 DVDD3 DVDD3 DVSS DVSS DVDD3 AVDD3 AGND SVDD3 SGND DVDD3 RFVDD3 RFGND TEZISLV CSO / RFOP NC NC DVDA DVDB DVDC DVDD DVDD3 DVSS IOA21 / V_ADIN0 DVDD18 DVSS DVSS TCK / V_ADIN6 TMS / V_ADIN5 TDI / V_ADIN4 TDO / V_ADIN7 OP_INP OP_OUT OP_INN NC DVDD18 DVSS IDACEXLP NC NC NC NC NC APLLCAP RFVDD18 RFGND18 Pin Arrangement (Top view) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com XV-DV232 86 1 2 3 4 1 2 3 4 C D F A B E Block Diagram DVD PUH Module Motor Drive Servo I/O Servo Processor Audio DSP Audio Output Audio DAC CVBS, Y/C Component Video SPDIF PCM System Parser CPPM/CPRM DRM 32-bit RISC Debug Port 108 MHz TV Encoder Video Processor MPEG-1/2 JPEG Video Decoder Deinterlacer Spindle Control Memory Controller System CPU Flash ROM DRAM GPIO IR/VFD RF Amplifier Video DAC www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com XV-DV232 87 5 6 7 8 5 6 7 8 C D F A B E Pin Function RF Interface (28) ADC for SACD (5) ALPC (4) No. Name Alt. I/O Function 226 RFGND18 Ground Analog ground 227 RFVDD18 Power Analog power 1.8V 250 NC 251 NC 252 OSP Analog output RF Offset cancellation capacitor connecting 253 OSN Analog output RF Offset cancellation capacitor connecting 254 RFGC Analog output RF AGC loop capacitor connecting for DVD-ROM 255 IREF Analog Input Current reference input. It generates reference current for RF path. Connect an external 15K resistor to this pin and AVSS. 256 AVDD3 Power Analog power 3.3V 1 AGND Ground Analog ground 2 DVDA Analog Input AC coupled input path A 3 DVDB Analog Input AC coupled input path B 4 DVDC Analog Input AC coupled input path C 5 DVDD Analog Input AC coupled input path D 6 DVDRFIP Analog Input AC coupled DVD RF signal input RFIP 7 DVDRFIN Analog Input AC coupled DVD RF signal input RFIN 8 MA Analog Input DC coupled main-beam RF signal input A 9 MB Analog Input DC coupled main-beam RF signal input B 10 MC Analog Input DC coupled main-beam RF signal input C 11 MD Analog Input DC coupled main-beam RF signal input D 12 SA Analog Input DC coupled sub-beam RF signal input A 13 SB Analog Input DC coupled sub-beam RF signal input B 14 SC Analog Input DC coupled sub-beam RF signal input C 15 SD Analog Input DC coupled sub-beam RF signal input D 16 CDFON Analog Input CD focusing error negative input 17 CDFOP Analog Input CD focusing error positive input 18 TNI Analog Input 3 beam satellite PD signal negative input 19 TPI Analog Input 3 beam satellite PD signal positive input No. Name Alt. I/O Function 20 MDI1 Analog Input Laser power monitor input 21 MDI2 Analog Input Laser power monitor input 22 LDO2 Analog Output Laser driver output 23 LDO1 Analog Output Laser driver output No. Name Alt. I/O Function 239 ADCVDD3 Power Analog 3.3V Power for ADC 240 NC 241 ADCVSS Ground Analog ground for ADC 242 NC 243 NC Reference Voltage (3) No. Name Alt. I/O Function 28 V2REFO Analog output Reference voltage 2.8V 29 V20 Analog output Reference voltage 2.0V 30 VREFO Analog output Reference voltage 1.4V www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com XV-DV232 88 1 2 3 4 1 2 3 4 C D F A B E Motor and Actuator Driver Interface (10) RF Data PLL Interface (9) Analog Monitor Output (7) No. Name Alt. I/O Function 24 SVDD3 Power Analog power 3.3V 25 CSO RFOP Analog output Central servo Positive main beam summing output 26 RFLVL RFON Analog output RFRP low pass, or Negative main beam summing output 27 SGND Ground Analog ground 31 FEO Analog output Focus error monitor output 32 TEO Analog output Tracking error monitor output 33 TEZISLV Analog output TE Slicing Level Analog Servo Interface (6) No. Name Alt. I/O Function 244 RFVDD3 Power Analog Power 245 RFRPDC Analog output RF ripple detect output 246 RFRPAC Analog Input RF ripple detect input(through AC-coupling) 247 HRFZC Analog Input High frequency RF ripple zero crossing 248 CRTPLP Analog output Defect level filter capacitor connecting 249 RFGND Ground Analog Ground No. Name Alt. I/O Function 230 JITFO Analog output The output terminal of RF jitter meter. 231 JITFN Analog Input The input terminal of RF jitter meter. 232 PLLVSS Ground Ground pin for data PLL and related analog circuitry. 233 IDACEXLP Analog output Data PLL DAC Low-pass filter 234 PLLVDD3 Power Power pin for data PLL and related analog circuitry. 235 LPFON Analog Output The negative output of loop filter amplifier 236 LPFIP Analog Input The positive input terminal of loop filter amplifier. 237 LPFIN Analog Input The negative input terminal of loop filter amplifier. 238 LPFOP Analog Output The positive output of loop filter amplifier No. Name Alt. I/O Function 34 OP_OUT Analog output Op amp output. 35 OP_INN Analog input Op amp negative input 36 OP_INP Analog input Op amp positive input 37 DMO Analog Output Disk motor control output. PWM output. 38 FMO Analog Output Feed motor control. PWM output. 39 TROPENPWM Analog Output Tray PWM output / Tray open output. 40 PWMOUT1 V_ADIN9 Analog Output 1st General PWM output, or Version AD input 9 41 TRO Analog Output Tracking servo output. PDM output of tracking servo compensator. 42 FOO Analog Output Focus servo output. PDM output of focus servo compensator 47 FG (Digital pin) V_ADIN8 LVTTL 3.3V Input, Schmitt Input, pull-up , with analog input path for V_ADIN8 Motor Hall sensor input, or Version AD input 8 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com XV-DV232 89 5 6 7 8 5 6 7 8 C D F A B E Micro Controller and Flash Interface (48) General Power / Ground (32) No. Name Alt. I/O Function 52, 97, 122, 152, 173, 221 DVDD18 Power 1.8V power pin for internal digital circuitry 43, 85, 116, 144, 163, 216 DVSS Ground 1.8V Ground pin for internal digital circuitry 46, 73, 80, 108, 127, 141, 155, 167, 182, 212 DVDD3 Power 3.3V power pin for internal digital circuitry 62, 94, 119, 134, 148, 161, 223 DVSS Ground 3.3V Ground pin for internal digital circuitry 204 DVDD3 Power 3.3V power pin Video DAC digital circuitry only 63 APLLCAP Analog Inout APLL External Capacitance connection 64 APLLVSS Ground Ground pin for audio clock circuitry 65 APLLVDD3 175 NC Power 3.3V Power pin for audio clock circuitry No. Name Alt. I/O Function 59 HIGHA0 Inout, 2-16MA, SR, PU Microcontroller address 8 75 HIGHA1 Inout, 2-16MA, SR, PU Microcontroller address 9 74 HIGHA2 Inout, 2-16MA, SR, PU Microcontroller address 10 72 HIGHA3 Inout, 2-16MA, SR, PU Microcontroller address 11 71 HIGHA4 Inout, 2-16MA, SR, PU Microcontroller address 12 70 HIGHA5 Inout, 2-16MA, SR, PU Microcontroller address 13 69 HIGHA6 Inout, 2-16MA, SR, PU Microcontroller address 14 68 HIGHA7 Inout, 2-16MA, SR, PU Microcontroller address 15 91 AD7 Inout, 2-16MA, SR Microcontroller address/data 7 88 AD6 Inout, 2-16MA, SR Microcontroller address/data 6 87 AD5 Inout, 2-16MA, SR Microcontroller address/data 5 86 AD4 Inout, 2-16MA, SR Microcontroller address/data 4 84 AD3 Inout, 2-16MA, SR Microcontroller address/data 3 83 AD2 Inout, 2-16MA, SR Microcontroller address/data 2 82 AD1 Inout, 2-16MA, SR Microcontroller address/data 1 81 AD0 Inout, 2-16MA, SR Microcontroller address/data 0 93 IOA0 Inout, 2-16MA, SR, PU Microcontroller address 0 / IO 78 IOA1 Inout, 2-16MA, SR, PU Microcontroller address 1 / IO 53 IOA2 Inout, 2-16MA, SR, PU Microcontroller address 2 / IO 54 IOA3 Inout, 2-16MA, SR, PU Microcontroller address 3 / IO 55 IOA4 Inout, 2-16MA, SR, PU Microcontroller address 4 / IO 56 IOA5 Inout, 2-16MA, SR, PU Microcontroller address 5 / IO 57 IOA6 Inout, 2-16MA, SR, PU Microcontroller address 6 / IO 58 IOA7 Inout, 2-16MA, SR, PU Microcontroller address 7 / IO 67 A16 Output, 2-16MA, SR Flash address 16 92 A17 Output, 2-16MA, SR Flash address 17 60 IOA18 Inout, 2-16MA, SR, SMT Flash address 18 / IO 61 IOA19 Inout, 2-16MA, SR, SMT Flash address 19 / IO 76 IOA20 Inout, 2-16MA, SR, SMT Flash address 20 / IO 89 IOA21 V_ADIN0 Inout, 2-16MA, SR, SMT Flash address 21 / IO While External FLASH size <= 2MB: Version AD input port 0, or GPIO www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com XV-DV232 90 1 2 3 4 1 2 3 4 C D F A B E No. Name Alt. I/O Function 90 ALE Inout, 2-16MA, SR, PU, SMT Microcontroller address latch enable 79 IOOE# Inout, 2-16MA, SR, SMT Flash output enable, active low / IO 66 IOWR# Inout, 2-16MA, SR, SMT Flash write enable, active low / IO 77 IOCS# Inout, 2-16MA, SR, PU, SMT Flash chip select, active low / IO 95 UWR# Inout, 2-16MA, SR, PU, SMT Microcontroller write strobe, active low 96 URD# Inout, 2-16MA, SR, PU, SMT Microcontroller read strobe, active low 98 UP1_2 Inout, 4MA, SR, PU, SMT Microcontroller port 1-2 99 UP1_3 Inout, 4MA, SR, PU, SMT Microcontroller port 1-3 100 UP1_4 Inout, 4MA, SR, PU, SMT Microcontroller port 1-4 101 UP1_5 Inout, 4MA, SR, PU, SMT Microcontroller port 1-5 102 UP1_6 SCL Inout, 4MA, SR, PU, SMT Microcontroller port 1-6 I2C clock pin 103 UP1_7 SDA Inout, 4MA, SR, PU, SMT Microcontroller port 1-7 I2C data pin 104 UP3_0 RXD Inout, 4MA, SR, PU, SMT Microcontroller port 3-0 8032 RS232 RXD 105 UP3_1 TXD Inout, 4MA, SR, PU, SMT Microcontroller port 3-1 8032 RS232 TXD 106 UP3_4 RXD SCL Inout, 4MA, SR, PU, SMT Microcontroller port 3-4 Hardwired RD232 RXD I2C clock pin 107 UP3_5 TXD SDA Inout, 4MA, SR, PU, SMT Microcontroller port 3-5 Hardwired RD232 TXD I2C data pin 111 IR Input, SMT IR control signal input 112 INT0# Inout, 2-16MA, SR, PU, SMT Microcontroller external interrupt 0, active low www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com XV-DV232 91 5 6 7 8 5 6 7 8 C D F A B E Audio Interface (14) No. Name Alt. I/O Function 208 SPMCLK SCLK0 Inout Audio DAC master clock of SPDIF input While SPDIF input is not used: Serial interface port 0 clock pin GPIO 209 SPDATA SDIN0 Inout Audio data of SPDIF input While SPDIF input is not used: Serial interface port 0 data-in GPIO 210 SPLRCK SDO0 Inout Audio left/right channel clock of SPDIF input While SPDIF input is not used: Serial interface port 0 data-out GPIO 211 SPBCK SDCS0 ASDATA5 Inout Audio bit clock of SPDIF input While SPDIF input is not used: Serial interface port 0 chip select Audio serial data 5 part I : DSD data sub-woofer channel or Microphone output GPIO 213 ALRCK Inout 4MA, PD, SMT Audio left/right channel clock Trap value in power-on reset: 1 : use external 373 0: use internal 373 214 ABCK Fs64 Output 4MA Audio bit clock Phase de-modulation 215 ACLK Inout, 4MA Audio DAC master clock 217 ASDATA0 Inout, 4MA, PD SMT Audio serial data 0 (Front-Left/Front-Right) DSD data left channel Trap value in power-on reset : 1 : manufactory test mode 0 : normal operation 218 ASDATA1 Inout, 4MA, PD SMT Audio serial data 1 (Left-Surround/Right-Surround) DSD data right channel Trap value in power-on reset : 1 : manufactory test mode 0 : normal operation While only 2 channels output: GPIO 219 ASDATA2 Inout, 4MA, PD SMT Audio serial data 2 (Center/LFE) DSD data left surround channel Trap value in power-on reset : 1 : manufactory test mode 0 : normal operation While only 2 channels output: GPIO 220 ASDATA3 Inout, 4MA, PD SMT Audio serial data 3 (Center-back/ Center-left-back/Center-right-back, in 6.1 or 7.1 mode) DSD data right surround channel Trap value in power-on reset : 1 : manufactory test mode 0 : normal operation While only 2 channels output: GPIO 222 ASDATA4 INT1# Inout, 4MA, PD SMT Audio serial data 4 (Down-mixed Left/Right) DSD data center channel Trap value in power-on reset : 1 : manufactory test mode 0 : normal operation While only 2 channels output: Microcontroller external interrupt 1 GPIO 224 MC_DATA INT2# Inout Microphone serial input While not support Microphone: Microcontroller external interrupt 2 GPIO 225 SPDIF Output, 2-16MA, SR : ON/OFF SPDIF output www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com XV-DV232 92 1 2 3 4 1 2 3 4 C D F A B E Video Interface (18) No. Name Alt. I/O Function 189 DACVDDC Power 3.3V power pin for VIDEO DAC circuitry 190 VREF Analog Bandgap reference voltage 191 FS Analog Full scale adjustment 192 YUV0 CIN Output 4MA, SR Video data output bit 0 Compensation capacitor 193 DACVSSC Ground Ground pin for VIDEO DAC circuitry 194 YUV1 Y Output 4MA, SR Video data output bit 1 Analog Y output 195 DACVDDB Power 3.3V power pin for VIDEO DAC circuitry 196 YUV2 C Output 4MA, SR Video data output bit 2 Analog chroma output 197 DACVSSB Ground Ground pin for VIDEO DAC circuitry 198 YUV3 CVBS Output 4MA, SR Video data output bit 3 Analog composite output 199 DACVDDA Power 3.3V power pin for VIDEO DAC circuitry 200 YUV4 Y/G Output 4MA, SR Video data output bit 4 Green or Y 201 DACVSSA Ground Ground pin for VIDEO DAC circuitry 202 YUV5 B/Cb/Pb Output 4MA, SR Video data output bit 5 Blue or CB 203 YUV6 R/Cr/Pr Output 4MA, SR Video data output bit 6 Red or CR 205 VSYN V_ADIN1 Inout 4MA, SR SMT Vertical sync input/output While no External TV-encoder: Vertical sync for video-input Version AD input port 1 GPIO 206 YUV7 INT3# ASDATA5 Inout 4MA, SR SMT Video data output bit 7 While no External TV-encoder: Microcontroller external interrupt 3 Audio serial data 5 part II : DSD data sub-woofer channel or Microphone output GPIO 207 HSYN INT4# V_ADIN2 Inout 4MA, SR SMT Horizontal sync input/output While no External TV-encoder: Horizontal sync for video-input Microcontroller external interrupt 4 Version AD input port 2 GPIO MISC (8) No. Name Alt. I/O Function 44 NC 45 NC 110 PRST# Input PU, SMT Power on reset input, active low 109 ICE Input PD, SMT Microcontroller ICE mode enable 228 XTALO Output 27M crystal out 229 XTALI Input 27M crystal in www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com XV-DV232 93 5 6 7 8 5 6 7 8 C D F A B E DRAM Interface (63)(sorted by position) No. Name Alt. I/O Function 188 NC 187 NC 186 NC 185 NC 184 NC 183 NC 166 RA4 165 RA5 164 RA6 162 RA7 160 RA8 159 RA9 Inout Inout Inout Inout Inout Inout DRAM address 4 157 CKE 156 RCLK 154 NC 153 NC output DRAM clock enable Inout DRAM check DRAM address 5 DRAM address 6 DRAM address 7 DRAM address 8 151 RA3 150 RA2 149 RA1 147 RA0 146 RA10 Inout Inout Inout Inout Inout DRAM address 3 DRAM address 2 DRAM address 1 DRAM address 0 DRAM address 10 DRAM address 9 181 NC 180 NC 179 DQM2 Inout Pull-Up GPIO 178 DQM3 Inout Pull-Up GPIO 177 RD24 Inout Non-pull GPIO 176 RD25 174 RD26 Inout Non-pull GPIO 172 NC 171 NC Inout Non-pull GPIO 170 RD29 Inout Non-pull GPIO 169 RD30 168 RD31 Inout Pull-Up GPIO 158 RA11 Inout Pull-Down DRAM address 11 Inout Pull-Up GPIO www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com XV-DV232 94 1 2 3 4 1 2 3 4 C D F A B E No. Name Alt. I/O Function 142 RCS# output DRAM chip select, active low 140 RAS# output DRAM row address strobe, active low 145 BA1 Inout DRAM bank address 1 143 BA0 Inout DRAM bank address 0 139 CAS# output DRAM column address strobe, active low 138 RWE# output DRAM Write enable, active low 137 DQM1 Inout Data mask 1 136 DQS1 Inout GPIO 135 RD8 Inout DRAM data 8 133 RD9 Inout DRAM data 9 132 RD10 Inout DRAM data 10 131 RD11 Inout DRAM data 11 130 RD12 Inout DRAM data 12 129 RD13 Inout DRAM data 13 128 RD14 Inout DRAM data 14 126 RD15 Inout DRAM data 15 125 RD0 Inout DRAM data 0 124 RD1 Inout DRAM data 1 123 RD2 Inout DRAM data 2 121 RD3 Inout DRAM data 3 120 RD4 Inout DRAM data 4 118 RD5 Inout DRAM data 5 117 RD6 Inout DRAM data 6 115 RD7 Inout DRAM data 7 114 DQS0 Inout Non-pull GPIO 113 DQM0 Inout Data mask 0 JTAG Interface (4) No. Name Alt. I/O Function 48 TDI V_ADIN4 Inout Serial interface port 3 data-out Version AD input port 4 GPIO 49 TMS V_ADIN5 Inout Serial interface port 3 data-in Version AD input port 5 GPIO 50 TCK V_ADIN6 Inout Serial interface port 3 clock pin Version AD input port 6 GPIO 51 TDO V_ADIN7 Inout Serial interface port 3 chip-select Version AD input port 7 GPIO www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com XV-DV232 95 5 6 7 8 5 6 7 8 C D F A B E GND 1 GND 56 GND 2 GVDD 55 GREG 3 BST_A 54 DVDD 4 PVDD_A 53 GND 5 PVDD_A 52 DGND 6 OUT_A 51 GND 7 OUT_A 50 PWM_AP 8 GND 49 PWM_AM 9 GND 48 RESET_AB 10 OUT_B 47 PWM_BM 11 OUT_B 46 PWM_BP 12 PVDD_B 45 DREG 13 PVDD_B 44 M1 14 BST_B 43 M2 15 BST_C 42 M3 16 PVDD_C 41 DREG_RTN 17 PVDD_C 40 PWM_CP 18 OUT_C 39 PWM_CM 19 OUT_C 38 RESET_CD 20 GND 37 PWM_DM 21 GND 36 PWM_DP 22 OUT_D 35 SD_AB 23 OUT_D 34 SD_CD 24 PVDD_D 33 OTW 25 PVDD_D 32 GREG 26 BST_D 31 GND 27 GVDD 30 GND 28 GND 29 TAS5122DCA (W51 DAMP ASSY : IC3201, IC3301, IC3401) • 30W Stereo Digital Amplifier Pin Arrangement (Top view) PWM Receiver Timing Control Gate Drive Protection A Gate Drive Gate Drive Gate Drive GREG GREG GREG GREG To Protection Blocks DREG Protection B 10 8 RESET_AB PWM_AP 54 BST_A 49 GND PWM Receiver OT Protection UVP Timing Control 12 PWM_BP 25 OTW Block Diagram 23 SD_AB 24 SD_CD 48 GND 13 DREG 26 GREG 30 GVDD 17 DREG_RTN 43 BST_B PWM Receiver Timing Control Gate Drive Protection C Gate Drive Gate Drive Gate Drive GREG GREG Protection D 20 18 RESET_CD PWM_CP 42 BST_C 37 GND PWM Receiver Timing Control 22 PWM_DP OUT_D 36 GND 31 BST_D 34,35 PVDD_D 32,33 38,39 PVDD_C OUT_C 40,41 50,51 PVDD_A OUT_A 52,53 46,47 PVDD_B OUT_B 44,45 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com XV-DV232 96 1 2 3 4 1 2 3 4 C D F A B E Pin Function No. Pin Name I/O Pin Function No. Pin Name I/O Pin Function 1 GND − Power ground 29 GND − Power ground 2 GND − Power ground 30 GVDD − Voltage supply to on-chip gate drive and digital supply voltage regulators 3 GREG − Gate drive voltage regulator decoupling pin, capacitor connected to GND 31 BST_D − HS bootstrap supply (BST), external capacitor to OUT_D required 4 DVDD − I/O reference supply input (3.3V) 32 PVDD_D − Power supply input for half-bridge D 5 GND − Power ground 33 PVDD_D − Power supply input for half-bridge D 6 DGND − Digital I/O reference ground 34 OUT_D O Output, half-bridge D 7 GND − Power ground 35 OUT_D O Output, half-bridge D 8 PWM_AP I Input signal (positive), half-bridge A 36 GND − Power ground 9 PWM_AM I Input signal (negative), half-bridge A 37 GND − Power ground 10 RESET_AB I Reset signal, active low 38 OUT_C O Output, half-bridge C 11 PWM_BM I Input signal (negative), half-bridge B 39 OUT_C O Output, half-bridge C 12 PWM_BP I Input signal (positive), half-bridge B 40 PVDD_C − Power supply input for half-bridge C 13 DREG − Digital supply voltage regulator decoupling pin, capacitor connected to GND 41 PVDD_C − Power supply input for half-bridge C 14 M1 I Mode selection pin 42 BST_C − HS bootstrap supply (BST), external capacitor to OUT_C required 15 M2 I Mode selection pin 43 BST_B − HS bootstrap supply (BST), external capacitor to OUT_B required 16 M3 I Mode selection pin 44 PVDD_B − Power supply input for half-bridge B 17 DREG_RTN − Digital supply voltage regulator decoupling return pin 45 PVDD_B − Power supply input for half-bridge B 18 PWM_CP I Input signal (positive), half-bridge C 46 OUT_B O Output, half-bridge B 19 PWM_CM I Input signal (negative), half-bridge C 47 OUT_B O Output, half-bridge B 20 RESET_CD I Reset signal, active low 48 GND − Power ground 21 PWM_DM I Input signal (negative), half-bridge D 49 GND − Power ground 22 PWM_DP I Input signal (positive), half-bridge D 50 OUT_A O Output, half-bridge A 23 SD_AB O Shutdown signal for half-bridges A and B 51 OUT_A O Output, half-bridge A 24 SD_CD O Shutdown signal for half-bridges C and D 52 PVDD_A − Power supply input for half-bridge A 25 OTW O Overtemperature warning output, open drain with internal pullup 53 PVDD_A − Power supply input for half-bridge A 26 GREG O Gate drive voltage regulator decoupling pin, capacitor connected to GND 54 BST_A − HS bootstrap supply (BST), external capacitor to OUT_A required 27 GND − Power ground 55 GVDD I Voltage supply to on-chip gate drive and digital supply voltage regulators 28 GND − Power ground 56 GND − Power ground www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com XV-DV232 97 5 6 7 8 5 6 7 8 C D F A B E AINR 1 CKS0 16 AINL 2 CKS2 15 CKS1 3 DIF 14 VCOM 4 PDN 13 AGND 5 SCLK 12 VA 6 MCLK 11 VD 7 LRCK 10 DGND 8 SDTO 9 No. Pin Name I/O Pin Function 1 AINR I R ch analog input 2 AINL I L ch analog input 3 CKS1 I Mode select 1 4 VCOM O Common voltage output, VA/2 bias voltage of ADC input 5 AGND − Analog Ground 6 VA − Analog power supply, 2.7-5.5V 7 VD − Digital power supply, 2.7-5.5V 8 DGND − Digital ground 9 SDTO O Audio serial data output "L" output at power-down mode. 10 LRCK I/O Output channel clock "L" output in master mode at power-down mode. 11 MCLK I Master clock input 12 SCLK I/O Audio serial data clock "L" output in master mode at power-down mode. 13 PDN I Power down mode "H": Power up, "L": Power down 14 DIF I Audio interface format "H": 24bit I2S compatible, "L": 24bit MSB justified 15 CKS2 I Mode select 2 16 CKS0 I Mode select 0 AK5357ET (W51 DVDMAIN ASSY : IC3003) • 96kHz 24-Bit ∆∑ ADC Pin Arrangement (Top view) Pin Function AINL LRCK SCLK SDTO DIF ∆∑ Modulator Decimation Filter 2 AINR ∆∑ Modulator Decimation Filter Serial I/O Interface 1 VD VCOM Voltage Reference Clock Driver 4 7 AGND 5 VA 6 CKS2 15 CKS1 3 CKS0 16 PDN 13 MCLK 11 DGND 8 10 12 9 14 Block Diagram www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com XV-DV232 98 1 2 3 4 1 2 3 4 C D F A B E TAS5508APAG (W51 DAMP ASSY : IC3101) • 8 ch Digital Audio PWM Processor Pin Arrangement (Top view) 1 VRA_PLL 2 PLL_FLT_RET 3 PLL_FLTM 4 PLL_FLTP 5 AVSS 6 AVSS 7 VRD_PLL 8 AVSS_PLL 9 AVDD_PLL 10 VBGAP 11 RESET 12 HP_SEL 13 PDN 14 MUTE 15 DVDD 16 DVSS VR_PWM 48 PWM_P_4 47 PWM_M_4 46 PWM_P_3 45 PWM_M_3 44 PWM_P_2 43 PWM_M_2 42 PWM_P_1 41 PWM_M_1 40 VALID 39 DVSS 38 BKND_ERR 37 DVDD 36 DVSS 35 DVSS 34 VR_DIG 33 17 VR_DPLL 18 OSC_CAP 19 XTL_OUT 20 XTL_IN 21 RESERVED 22 RESERVED 23 RESERVED 24 SDA 25 SCL 26 LRCLK 27 SCLK 28 SDIN4 29 SDIN3 30 SDIN2 31 SDIN1 32 PSVC RESERVED 64 MCLK 63 PWM_HPPR 62 PWM_HPMR 61 PWM_HPPL 60 PWM_HPML 59 PWM_P_6 58 PWM_M_6 57 PWM_P_5 56 PWM_M_5 55 DVDD_PWM 54 DVSS_PWM 53 PWM_P_8 52 PWM_M_8 51 PWM_P_7 50 PWM_M_7 49 Pin Functions No. Pin Name I/O Pin Function 1 VRA_PLL − Voltage reference for PLL analog supply 1.8 V. 2 PLL_FLT_RET O PLL external filter return 3 PLL_FLTM O PLL negative input. Connected to PLL_FLT_RTN via an RC network 4 PLL_FLTP I PLL positive input. Connected to PLL_FLT_RTN via an RC network 5 AVSS − Analog ground 6 AVSS − Analog ground 7 VRD_PLL − Voltage reference for PLL digital supply 1.8 V. 8 AVSS_PLL − Analog ground for PLL. 9 AVDD_PLL − 3.3-V analog power supply for PLL 10 VBGAP − Band gap voltage reference. 11 RESET I System reset input, active low. 12 HP_SEL I Headphone in/out selector. 13 PDN I Power down, active low. PDN powers down all logic and stops all clocks whenever a logic low is applied. 14 MUTE I Soft mute of outputs, active low (Muted signal = a logic low, normal operation = a logic high) 15 DVDD − Digital power 3.3-V supply for digital core and most of I/O buffers 16 DVSS − Digital ground for digital core and most of I/O buffers 17 VR_DPLL − Voltage reference for digital PLL supply 1.8 V. 18 OSC_CAP O Oscillator capacitor 19 XTL_OUT O XTL_OUT and XTL_IN are the only LVCMOS terminals on the device. 20 XTL_IN I XTL_OUT and XTL_IN are the only LVCMOS terminals on the device. 21 RESERVED − Connect to digital ground 22 RESERVED − Connect to digital ground 23 RESERVED − Connect to digital ground 24 SDA I/O I2C serial control data interface input / output www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com XV-DV232 99 5 6 7 8 5 6 7 8 C D F A B E No. Pin Name I/O Pin Function 25 SCL I I2C serial control clock input output 26 LRCLK I Serial audio data left / right clock (sampling rate clock) 27 SCLK I Serial audio data clock (shift clock) 28 SDIN4 I Serial audio data 4 input is one of the serial data input ports. SDIN4 supports four discrete (stereo) data formats and is capable of inputting data at 64 Fs. 29 SDIN3 I Serial audio data 3 input is one of the serial data input ports. SDIN3 supports four discrete (stereo) data formats and is capable of inputting data at 64 Fs. 30 SDIN2 I Serial audio data 2 input is one of the serial data input ports. SDIN2 supports four discrete (stereo) data formats and is capable of inputting data at 64 Fs. 31 SDIN1 I Serial audio data 1 input is one of the serial data input ports. SDIN1 supports four discrete (stereo) data formats and is capable of inputting data at 64 Fs. 32 PSVC O Power supply volume control PWM output 33 VR_DIG − Voltage reference for digital core supply 1.8 V. 34 DVSS − Digital ground 35 DVSS − Digital ground 36 DVDD − 3.3-V digital power supply 37 BKND_ERR I Active low. A backend error sequence is generated by applying logic low to this terminal. 38 DVSS − Digital ground 39 VALID O Output indicating validity of PWM outputs active high 40 PWM_M_1 O PWM 1 output (differential - ) 41 PWM_P_1 O PWM 1 output (differential +) 42 PWM_M_2 O PWM 2 output (differential - ) 43 PWM_P_2 O PWM 2 output (differential +) 44 PWM_M_3 O PWM 3 output (differential - ) 45 PWM_P_3 O PWM 3 output (differential +) 46 PWM_M_4 O PWM 4 output (differential - ) 47 PWM_P_4 O PWM 4 output (differential +) 48 VR_PWM − Voltage reference for digital PWM core supply 1.8 V. 49 PWM_M_7 O PWM 7 (Line out L) output (differential - ) 50 PWM_P_7 O PWM 7 (Line out L) output (differential +) 51 PWM_M_8 O PWM 8 (Line out R) output (differential - ) 52 PWM_P_8 O PWM 8 (Line out R) output (differential +) 53 DVSS_PWM − Digital ground for PWM 54 DVDD_PWM − 3.3-V digital power supply for PWM 55 PWM_M_5 O PWM 5 output (differential - ) 56 PWM_P_5 O PWM 5 output (differential +) 57 PWM_M_6 O PWM 6 output (differential - ) 58 PWM_P_6 O PWM 6 output (differential +) 59 PWM_HPML O PWM left channel headphone (differential - ) 60 PWM_HPPL O PWM left channel headphone (differential +) 61 PWM_HPMR O PWM right channel headphone (differential - ) 62 PWM_HPPR O PWM right channel headphone (differential +) 63 MCLK I MCLK is a 3.3-V clock master clock input. The input frequency of this clock can range from 4 MHz to 50 MHz. 64 RESERVED − Connect to digital ground www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com XV-DV232 100 1 2 3 4 1 2 3 4 C D F A B E PT6315 (W51 DISPLAY ASSY : IC5901) • FL Driver IC Pin Arrangement (Top view) 1 LED1 2 LED2 3 LED3 4 LED4 5 OSC 6 DOUT 7 DIN 8 CLK 9 STB 10 K1 11 K2 SG19/GR10 33 SG18/GR11 32 SG17/GR12 31 VEE 30 SG16/KS16 29 SG15/KS15 28 SG14/KS14 27 SG13/KS13 26 SG12/KS12 25 SG11/KS11 24 SG10/KS10 23 12 VSS 13 VDD 14 SG1/KS1 15 SG2/KS2 16 SG3/KS3 17 SG4/KS4 18 SG5/KS5 19 SG6/KS6 20 SG7/KS7 21 SG8/KS8 22 SG9/KS9 VSS 44 VDD 43 GR1 42 GR2 41 GR3 40 GR4 39 SG24/GR5 38 SG23/GR6 37 SG22/GR7 36 SG21/GR8 35 SG20/GR9 34 DIN Serial Data Interface 7 SG1/KS1 14 SG2/KS2 15 SG3/KS3 16 SG4/KS4 17 SG5/KS5 18 SG6/KS6 19 SG7/KS7 20 SG8/KS8 21 SG9/KS9 22 SG10/KS10 23 SG11/KS11 24 SG12/KS12 25 SG13/KS13 26 SG14/KS14 27 SG15/KS15 28 SG16/KS16 29 SG17/GR12 31 SG18/GR11 32 SG19/GR10 33 SG20/GR9 34 SG21/GR8 35 SG22/GR7 36 SG23/GR6 37 SG24/GR5 38 DOUT 6 CLK 8 STB 9 OSC 5 LED1 1 OSC Timing Generator Dimming Circuit Key Matrix Memory Grid Driver Display Memory (24 bits×12 Words) Segment Driver/ Grid Driver/ Key Scan output GR1 42 GR2 41 GR3 40 GR4 39 K1 10 K2 11 VDD 13 VDD 43 VSS 12 VSS 44 VEE 30 LED Driver LED2 2 LED3 3 LED4 4 Control Block Diagram www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com XV-DV232 101 5 6 7 8 5 6 7 8 C D F A B E Pin Functions No. Pin Name I/O Pin Function 1 LED1 O LED output 2 LED2 O LED output 3 LED3 O LED output 4 LED4 O LED output 5 OSC I Oscillator input 6 DOUT O Data output (N-ch, open-drain) This pin outputs serial data at the falling edge of the shift clock. 7 DIN I Data input This pin inputs serial data at the rising edge of the shift clock. 8 CLK I Clock input This pin reads serial data at the rising edge and outputs data at the falling edge. 9 STB I Serial interface strobe The data input after the STB has fallen is processed as a command. 10 K1 I Key data input The data inputted to this pin is latched at the end of the display cycle. 11 K2 I Key data input The data inputted to this pin is latched at the end of the display cycle. 12 VSS − Logic ground 13 VDD − Logic power supply 14 SG1/KS1 O High-voltage segment output / Key source 15 SG2/KS2 O High-voltage segment output / Key source 16 SG3/KS3 O High-voltage segment output / Key source 17 SG4/KS4 O High-voltage segment output / Key source 18 SG5/KS5 O High-voltage segment output / Key source 19 SG6/KS6 O High-voltage segment output / Key source 20 SG7/KS7 O High-voltage segment output / Key source 21 SG8/KS8 O High-voltage segment output / Key source 22 SG9/KS9 O High-voltage segment output / Key source 23 SG10/KS10 O High-voltage segment output / Key source 24 SG11/KS11 O High-voltage segment output / Key source 25 SG12/KS12 O High-voltage segment output / Key source 26 SG13/KS13 O High-voltage segment output / Key source 27 SG14/KS14 O High-voltage segment output / Key source 28 SG15/KS15 O High-voltage segment output / Key source 29 SG16/KS16 O High-voltage segment output / Key source 30 VEE − Pull-down level 31 SG17/GR12 O High-voltage segment output / Grid output 32 SG18/GR11 O High-voltage segment output / Grid output 33 SG19/GR10 O High-voltage segment output / Grid output 34 SG20/GR9 O High-voltage segment output / Grid output 35 SG21/GR8 O High-voltage segment output / Grid output 36 SG22/GR7 O High-voltage segment output / Grid output 37 SG23/GR6 O High-voltage segment output / Grid output 38 SG24/GR5 O High-voltage segment output / Grid output 39 GR4 O High-voltage grid output 40 GR3 O High-voltage grid output 41 GR2 O High-voltage grid output 42 GR1 O High-voltage grid output 43 VDD − Logic power supply 44 VSS − Logic ground www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com XV-DV232 102 1 2 3 4 1 2 3 4 C D F A B E QUAL 1 RCLK 16 RDATA 2 (NC) 15 VREF 3 XO 14 MUX 4 XI 13 VDD1 5 VDD2 12 VSS1 6 VSS2 11 VSS3 7 T1 10 CMP 8 T2 9 No. Pin Name I/O Pin Function 1 QUAL O Output signal quality Good: H, Bad: L 2 RDATA O Demodulation data output 3 VREF − Reference voltage 4 MUX I Composite signal input 5 VDD1 − Analog power supply 6 VSS1 − Analog ground 7 VSS3 − Analog ground 8 CMP − Comparator 9 T1 I Input for test H: Internal clock stop, L: Operation 10 T2 I Input for test (Open or connect to GND.) 11 VSS2 − Digital ground 12 VDD2 − Digital power supply 13 XI I Connect a 4.332MHz crystal. 14 XO O Connect a 4.332MHz crystal. 15 (NC) − Non connection 16 RCLK O Demodulation clock (1187.5kHz) output BU1924FS (W51 DVDMAIN ASSY : IC5701) • RDS Demodulator Pin Arrangement (Top view) Pin Function MUX QUAL RDATA 4 VREF 3 VDD1 8th Switched Capacitor Filter Deferential Decoder Biphase Decoder PLL 1187.5Hz Clock Comparator PLL 57kHz RDS/ARI 5 VDD2 4 VSS1 6 12VSS2 11 Test XI 13 XO 14 T1 10 T2 9 CMP 8 VSS3 7 1 RCLK 16 2 Block Diagram 100kΩ 100kΩ 120kΩ www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com XV-DV232 103 5 6 7 8 5 6 7 8 C D F A B E CS 1 VCC 8 SK 2 NC 7 DI 3 TEST 6 DO 4 GND 5 No. Pin Name I/O Pin Function 1 CS I Chip select input 2 SK I Serial clock input 3 DI I Serial data input 4 DO O Serial data output 5 GND − Ground 6 TEST − Test (Connect to GND or VCC.) 7 NC − Non connection 8 VCC − Power supply S-93C46BD01-J8T1 (W51 DVDMAIN ASSY : IC5503) • Serial EEPROM Pin Arrangement (Top view) Pin Function DO DI Memory Array Data Register Output Buffer Mode Decode Logic Address Decoder 3 Clock Pulse Monitor Circuit Voltage Detector Clock Generation Circuit 4 VCC 8 GND 5 Block Diagram CS 1 SK 2 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com XV-DV232 104 1 2 3 4 1 2 3 4 C D F A B E 8. PANEL FACILITIES Front panel 6 0 7 1 Display See Display above for detailed information. 2 0 OPEN/CLOSE Opens/closes the disc tray. 3 6 DVD/CD Selects the DVD/CD function and starts/ pauses/resumes playback. 4 7 Stops playback. 5 FM/AM Selects the tuner function and toggles between FM/AM bands. 6 VOLUME buttons Adjusts the volume. 7 STANDBY/ON Switches the system on or into standby. 8 PHONES jack Headphone jack. 1 STANDBY/ON Switches the system on or into standby. 2 Function select buttons Selects the source you want to listen to (DVD/ CD. TUNER, LINE) 3 Number buttons Select chapters/tracks from a disc directly. Press DVD/CD to access these controls: SHIFT+AUDIO Selects audio channel/language. SHIFT+SUBTITLE Displays/changes the subtitles. SHIFT+ANGLE Changes camera angle during DVD multi- angle scene playback. SHIFT+ZOOM Changes the screen zoom level.. DVD/CD FM/AM - + STANDBY/ON VOLUME OPEN/CLOSE 4 5 6 7 8 3 2 1 AUDIO SUBTITLE ANGLE ZOOM STANDBY/ON MUTE DVD/CD FM/AM TUNER LINE SYSTEM SETUP HOME MENU DVD MENU TOP MENU RETURN TEST TONE SOUND MODE SHIFT CLEAR SLEEP DISPLAY VOLUME 1 2 3 4 5 6 7 8 9 0 TUNE TUNE ST ST ENTER SURROUND FRONT SURROUND 1 2 4 6 3 5 7 8 9 10 11 12 13 14 15 Remote control www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com XV-DV232 105 5 6 7 8 5 6 7 8 C D F A B E 4 HOME MENU Displays (or exits) the on-screen menu for Initial Settings, Play Mode functions, etc. SHIFT+SYSTEM SETUP Use to make various system and surround sound settings. 5 Cursor buttons, ENTER and tuning buttons Cursor buttons Use the cursor buttons (»/«/|/\)to navigate on-screen displays and menus. ENTER Selects an option or executes a command. TUNE +/- Tunes the radio. ST +/- Selects station presets when listening to the radio. 6 SOUND MODE Accesses the sound menu to adjust the SFC Mode, bass and treble, etc. SHIFT+TEST TONE Outputs the test tone (for speaker setup). 7 Disc playback controls See Basic playback controls and Playing discs on for an explanation of these controls. 8 SHIFT Some of the buttons have alternate functions (they are outlined on the remote control). Press and hold SHIFT to access these. 9 CLEAR Clears an entry. 10 MUTE Mutes the sound (press again to cancel). 11 VOLUME +/- Adjusts the volume. 12 DVD MENU Press to display a DVD disc menu, or the Disc Navigator. SHIFT+TOP MENU Displays the top menu of a DVD disc in the play positionóthis may be the same as pressing DVD MENU. 13 RETURN Returns to a previous menu screen. 14 DISPLAY Displays/changes disc information shown on-screen or to display RDS information. SHIFT+FRONT SURROUND This button has no effect with XV-DV535W. Selects a Front Surround listening mode. 15 SLEEP Press to set the sleep timer. SHIFT+SURROUND Selects a Surround mode. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com XV-DV232 106 1 2 3 4 1 2 3 4 C D F A B E Display 1 DTS Lights during playback of a DTS source 2 SOUND Lights when the SFC Modes or the tone controls (treble, bass or bass boost) are active 3 Indicator is off when no sound is output through the wireless speaker (for example, when the TUNER or LINE function is selected). 4 RPT and RPT-1 RPT lights during repeat play. RPT-1 lights during repeat one-track play 5 REC MODE Lights when Rec Mode is on. 6 PGM Lights during program play. 7 Tuner indicators - Lights when a broadcast is being received. - Lights when a stereo FM broadcast is being received in auto stereo mode. - Lights when FM mono reception is selected. - (European model only) Lights when in one of the RDS display or search modes. 8 RDM Lights during random play. 16 PRGSVE (Except European model) Lights when progressive scan video output is selected. 15 F.SURR. (Except XV-DV535W) Lights when the Front Surround listening mode is selected. 9 kHz / MHz Indicates the frequency unit shown in the character display (kHz for AM, MHz for FM). 10 Character display 11 Lights when sleep timer is active 12 � Lights when a disc is playing. 13 2 PL II Lights during Dolby Pro Logic II decoding 14 2 D Lights during playback of a Dolby Digital source. SOUND PRGSVE DTS F.SURR. 2PL 2D W REC MODE RPT -1 kHz PGM MHz RDM 5 12 9 7 4 11 13 2 16 15 14 1 3 10 6 8 (XV-DV535W only) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com XV-DV232 107 5 6 7 8 5 6 7 8 C D F A B E Troubleshooting Problem Remedy SND. DEMO shows in the display and the unit can't be controlled. • Press and hold � (stop) on the front panel for about ve seconds. The disc tray ejects automatically to indicate the Sound Demo mode is disabled. TRAYLOCK shows in the display and the tray can't be ejected. • Press and hold � (eject) on the front panel for about eight seconds. Then the tray can be opened/closed using � (eject). www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com XV-DV232 108 1 2 3 4 1 2 3 4 C D F A B E Service Remote Control Unit GGF1381 DVD Test Disc (DVD-Video) GGV1025 adjustment, diagnosis Name Jig No. Remarks Check of DVD-Video CD Test Disc STD-905 Check of CD DVD Data Disc GGV1175 diagnosis (ID data setting) 7 Jigs list Lubricating Oil GYA1001 GEM1036 Daifree Name Lubricants and Glues No. Remarks refer to "2.3 05 LOADER ASSY" refer to "2.3 05 LOADER ASSY" GEM1037 Silicone Adhesive refer to "2.4 TM ASSY VK1AVC" 7 Lubricants and Glues list Speaker Cable with terminal SDS1174 (FL/WHITE) SDS1175 (FR/RED), SDS1176 (SL/BLUE) SDS1177 (SR/GRAY), SDS1178 (C/GREEN) For checking audio at the SP terminal Before shipping out the product, be sure to clean the following positions by using the prescribed cleaning tools: Position to be cleaned Cleaning tools Pickup leneses Cleaning liquid : GEM1004 Cleaning paper : GED-008 7 CLEANING www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com
