PIONEER ELECTRONIC CORPORATION 4-1, Meguro 1-Chome, Meguro-ku, Tokyo 153-8654, Japan PIONEER ELECTRONICS SERVICE INC. P.O.Box 1760, Long Beach, CA 90801-1760 U.S.A. PIONEER ELECTRONIC [EUROPE] N.V. Haven 1087 Keetberglaan 1, 9120 Melsele, Belgium PIONEER ELECTRONICS ASIACENTRE PTE.LTD. 501 Orchard Road, #10-00, Wheelock Place, Singapore 238880 C PIONEER ELECTRONIC CORPORATION 1998 K-ZES. APR. 1998 Printed in Japan ORDER NO. CRT2217 MULTI-PLAY CD ADAPTOR CD-P75FM UC,EW Service Manual - This additional service manual is designed to be used together with Model CD-P70FM/UC,EW Service Manual CRT1582. Refer to it for finding parts numbers and adjustment,etc. which are not shown in this manual. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 2 CD-P75FM CAUTION This service manual is intended for qualified service technicians; it is not meant for the casual do-it-yourselfer. Qualified technicians have the necessary test equipment and tools, and have been trained to properly and safely repair complex products such as those covered by this manual. Improperly performed repairs can adversely affect the safety and reliability of the product and may void the warranty. If you are not qualified to perform the repair of this product properly and safely; you should not risk trying to do so and refer the repair to a qualified service technician. WARNING Lead in solder used in this product is listed by the California Health and Welfare agency as a known reproductive toxi- cant which may cause birth defects or other reproductive harm (California Health and Safety Code, Section 25249.5). When servicing or handling circuit boards and other components which contain lead in solder, avoid unprotected skin contact with the solder. Also, when soldering do not inhale any smoke or fumes produced. SAFETY INFORMATION www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 3 CD-P75FM PACKING METHOD(Page 2-9) - Parts List *:Non Spare Part Part No. Mark No. Description CD-P70FM/UC,EW CD-P75FM/UC,EW 5-2 Fastener(x3)(Rough) CNM-667 CNM5318 7-4-1 Screw(x2)(UC) PMS30P050FZK IMS30P050FZK 8 Carton(UC) CZH6027 CZH6131 Carton(EW) CZH6029 CZH6133 9 Contain Box(UC) CZH6028 CZH6132 Contain Box(EW) CZH6030 CZH6134 10 Owner's Manual(UC) CZR3137 CZR3185 Owner's Manual(EW) CZR3138 CZR3186 Owner's Manual(EW) Not used CZR3190 * 10-2 Warranty Card(EW) CRY1071 CRY1087 * 11 Remote Control Unit CZE3134 CZE3239 * 11-2 Remote Control Assy CXA6570 CXB2969 Caution Card(UC) Not used CZP3284 EXPLODED VIEW PARTS LIST(Page 1-13) - Chassis Part No. Mark No. Description CD-P70FM/UC,EW CD-P75FM/UC,EW 2 Button CAC3737 CZA6070 3 Grille Unit CZX3145 CZX3225 15 Screw PMS30P050FZK IMS30P050FZK 23 Case CZN6280 CZN7556 24 Screw BMZ30P060FMC BSZ30P060FMC 39 Display Unit(UC) CZX3146 CZX3223 Display Unit(EW) CZX3147 CZX3226 40 Hideaway Unit(UC) CZX3148 CZX3224 Hideaway Unit(EW) CZX3149 CZX3227 41 Remote Control Assy CXA6570 CXB2969 - Owner's Manual Model Part No. Language CD-P75FM/EW CZR3186 English, Italian, French CZR3190 German, Dutch, Spanish www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 4 CD-P75FM A 1 2 3 4 B C D 1 2 3 4 SCHEMATIC DIAGRAM Note: When ordering service parts, be sure to refer to “EXPLODED VIEWS AND PARTS LIST” or “ELECTRICAL PARTS LIST”. Q DT Q108 2SB1197K R133 4R7K R132 5R6K A.SENS R107 6R8K HIDE-AWAY UNIT R111 1K 1/2W R103 10K D105 HZS7(C1) Q103 2SC2412K 4 ACC B.UP IN B.UP OUT 1 4 3 2 GND 1A FUSE 4A FUSE R102 10K R104 47K C109 R1 C110 1R0/50 D104 HZS7(C1) R110 10K Q102 2SC2412K R105 47K B.SENS BACK.UP R106 6R8K D5V R112 0R0 R108 47K PREN AVSS AVREF RESET 60 DISB 59 IPPW 58 RX 57 TX 56 55 SYSPW 54 ILMPW 53 AUXB 52 51 50 49 48 47 MUTE 46 PEE 45 44 43 BUSMUTE 42 41 40 39 38 37 36 35 34 VSS 33 32 31 30 29 28 27 26 25 24 23 22 21 SLSW 61 BSENS 62 ASENS 63 64 65 66 67 VDD 68 X2 69 X1 70 IC VPP 71 72 TEST IN 73 TCK TSO TSI PLCE PLCK AVDD 74 AVREF0 75 76 77 78 79 80 KYDT DPDT SWVDD PLDO IC103 PD4953A R123 120K C115 2R2/50 R124 10K C130 24P C131 24P X101 CSS1303 6.29MHz S101 CZS2032 D110 1SS355 R1 47 TEST C105 100/10 C106 R022 1 2 3 IC102 D5V D5V GND Q116 DTC114EK VDD D101 ERA15-02 D102 ERA15-02 R115 3R3K Q101 2SD1858 C103 2200/16 CCH1001 C104 33/10 R101 12K D103 HZS6L(B1) R113 2R2K R114 4R7K Q105 2SB1197K C102 1000/16 CZC2055 CCG1006 C101 CN101 L101 1mH 1 2 3 1 5 8 R116 62 R117 100 R118 100 CN102 1 2 3 4 5 6 7 8 BUS1 BUS2 PA0051AM IC101 R119 1K R120 1K Q106 DTA114EK R122 47K R121 47K IC102: S-80731AN-DY D5V GND BACK.UP TX RX IPPW SYSPW R139 5R6K Q112 DTC114EK R138 22 R140 10K Q113 2SB1197K D116 1SS355 C124 33/10 A5V PREN ASL.VCC GND 11 1 10 2 Aout Ain Din Dout Acnt Dcnt 13 12 14 TC4066BF IC304 L R C112 R001 C113 R001 C114 R01 D109 DAP202K PREN ASL.VCC 2 4 C111 R1 7 C303 1R0/50 R301 180 1 IC301 TA2050S MUTE C326 R01 GND 4 8 9 3 Bin Bout Cin Cout Bcnt Ccnt 5 6 7 R345 27K L R C315 2200P VR301 CZC2050 33K(B) A5V C34 1/5 R349 3R9K R350 3R9K R351 3R9K C121 R01 R352 1R8K R353 3R9K R316 1R5K X301 CZS2030 VR303 CZC2051 220K(B) R319 100 C324 10P R340 68K C325 10/16 C322 10/16 C323 R01 RIN 1 2 3 GND 4 5 OSCIN 6 7 OSCOUT 8 9 LIN 18 17 16 15 VCC 14 M PX 13 12 PLOUT 11 10 IC302 BA1405F C319 470P R315 3R3K C320 470P R347 680 R348 680 R346 27K R356 7R5K R355 7R5K L R C317 R22/50 C318 R22/50 C316 2200P C313 *** C314 *** R313 *** R314 *** 2 3 4 5 6 7 8 9 R307 2K R308 2K C310 4700P C309 4700P R310 13K R309 13K L301 L302 C307 10/16 C321 22/10 C308 10/16 C311 3900P C312 3900P R311 7R5K R312 7R5K 11 3 6 10 9 C305 1R0/50 C306 1R0/50 C301 R1 C302 R1 R305 1K R306 1K R302 180 R304 22K R303 22K C304 1R0/50 /EW /UC 39K 56K 1200P 1500P R313,R314 C313,C314 *** C327 220P SYSTEM CONTROLLER 38KHz ACC SENSE BACK UP SENSE 5V REGULATOR DRIVER/RECEIVER ISOLATOR FM STEREO MODULATOR NC IP BUS INPUT CEK1016 CEK1020 A F RESET A F www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 5 CD-P75FM 5 6 7 8 A B C D 5 6 7 8 CZA3247 C118 R022 Q109 2SD2395 8.2V Q107 DTC114EK D106 1SS355 C116 10/16 C117 10/16 R134 2R2K D113 HZS9(B2) Q108 B1197K R132 5R6K GND PREN 12 3 AVSS 4 56 AVREF 7 25 24 23 22 21 20 19 TCK 18 TSO 17 TSI 16 15 PLCE 14 PLCK 13 11 76 77 78 79 80 KYDT 8 DPDT 9 SWVDD 10 PLDO 12 R128 2R2K R129 2R2K D111 DA204K D112 DA204K R144 0R0 R131 2R2K R130 2R2K R126 5R6K R143 100K R109 SW+B Q201 2SD1767 R202 5R6K C201 R047 DISPLAY UNIT CN201 CN103 4 1 D201 DTZ6R2A 4 3 R201 562 C202 10/6R3 C203 10/6R3 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 COM 3 COM 2 COM 1 COM 0 SEG6 SEG7 SEG8 SEG9 SEG10 SEG11 SEG12 SEG13 SEG14 SEG15 SEG16 SEG17 SEG18 SEG19 C205 R1 C206 R1 X201 CSS1084 4.91MHz VSS 1 X1 2 X0 3 RST 4 MOD1 5 MOD0 6 7 SEG13 60 SEG14 59 SEG15 58 SEG16 57 SEG17 56 SEG18 55 SEG19 54 SEG20 53 SEG21 52 SEG22 51 SEG23 50 SEG24 49 SEG25 48 SEG26 47 SEG27 46 SEG28 45 SEG29 44 SEG30 43 SEG31 42 SEG32 41 SEG33 40 SEG34 39 SEG35 38 SEG36 37 SEG37 36 NC 35 NC 34 NC 33 NC 32 31 30 29 28 27 26 25 24 VDD 23 KST1 22 KST2 21 SEG12 61 SEG11 62 SEG10 63 SEG9 64 SEG8 65 SEG7 66 SEG6 67 NC 68 NC 69 NC 70 NC 71 NC 72 NC 73 KST3 20 KST4 19 KST5 18 KST6 17 KD1 16 KD2 15 KD3 14 KD4 13 11 COM 3 74 COM 2 75 COM 1 76 COM 0 77 V3 78 V2 79 V1 80 KYDT 8 OPDT 9 REMIN 10 ILMI 12 IC201 PD6122A MB89820 C204 R1 D203 DA204K D202 DA204K 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 SEG20 SEG21 SEG22 SEG23 SEG24 SEG25 SEG26 SEG27 SEG28 SEG29 SEG30 SEG31 SEG32 SEG33 SEG34 SEG35 SEG36 SEG37 R209 470 R207 470 R208 470 VDD S201 SW PUSH R210 470 KYDT DPDT GND 3 R205 22K Q203 DTC114EK IL202 IL201 2 R206 1R5K 2 1 Q202 2SA1036K 100K 303 MHz R127 47K TEST Q113 2SB1197K R342 2R2K R341 1K R343 0R0 Q306 2SD1781K 8.0v IC105 HA178L05 1 2 3 Q114 2SD1781K R141 2R7K IL201,202 CZE3195 A5V 5.0V 1 3 RELAY IC202 RPM-578C8R RY101 CZS2026 Q115 DTC114GK 2 R142 2R2K D118 1SS133 D302 1SS355 8.0v 8.7v C129 R22/50 C128 100/10 C123 R047 C127 33/10 D117 HZS9L(C2) C126 100/16 R136 1R2K C125 100/10 R137 10K XOUT 1 XIN 2 CE 3 DA 4 CK 5 DO 6 SD 7 IFIN 8 P3 9 PD2 17 PD1 16 VDD 15 FM IN 14 AM IN 13 P2 12 P1 11 P0 10 VSS 18 IC104 BU2616F D308 HZS9L(C2) C350 47/16 X102 X102: CSS1030 D307 HZS9(B2) C122 33/10 7.2MHz C349 470/10 C119 27P C120 27P 8.7v A5V PREN ASL.VCC C348 1/50 R351 3R9K C121 R01 R353 3R9K 354 10K Q110 2SC2412K LN D5V D114 1SS355 R135 10K D115 1SS355 R321 56K R335 100 C342 R01 D303 1SS133 L305 2R2uH Q111 2SC2412K LN R327 3R3K 7.3v R334 2R2K R333 100K R336 470K R338 1R5K Q305 2SC2413K R332 56 C343 1R0 C344 3R0 L306 R68u VR305 CZC2053 1K(B) 1.3v 6.5v 2.2v ANT PLUG CN301 ANT JACK CN302 CN303 CN304 C346 R01 C345 R01 R337 150K Q304 2SC2413K C341 18P R339 1R2K 2.9v R330 3R3K R329 10K D306 KV1440 C338 10P C339 1P C340 33P Q303 2SC2413K R328 10K C337 20P R331 10K 4.2V 87.7M VF L304 C347 R01 R326 8R2K C336 1 R325 10K TP301 7.3v 3.6v L303 CZT2004 5mH C330 1 C334 10/16 C331 10/16 C329 15P VR304 CZC2050 33K(B) R324 10K C333 330P C335 680P C332 1800P 5 6 7 8 4 IC303 UPC4570G D305 RB421D D304 RB421D COMP R323 47K /EW /UC 18K 10K R322 R322 *** *** R318 10K R319 100K R317 10K TC301 CZC2031 C328 R1 R320 100K 3 2 1 IC303 UPC4570G POWER LCD DRIVER R PLL FREQUENCY SYNTHESIZER REGULATOR REMOTE CONTROL SENSOR RF CIRCUIT B A F www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 6 CD-P75FM A 1 2 3 4 B C D 1 2 3 4 A F NOTE FOR PCB DIAGRAMS 1. The parts mounted on this PCB include all necessary parts for several destination. For further information for respective destinations, be sure to check with the schematic dia- gram. 2. Viewpoint of PCB diagrams PCB CONNECTION DIAGRAM HIDEAWAY UNIT Capacitor Connector P.C.Board Chip Part SIDE A SIDE B HIDEAWAY UNIT A F JACK GND CN303 CN304 + C102 L101 1122 1122 1122 CN101 C101 RY101 + C129 L304 CZK2040 D101 R110 D118 PLUG CN301 D104 D103 + C104 D303 R111 Q101 D105 TP301 GND VF D102 CN302 + C110 VR305 RF.LEVEL 102 L305 + C103 + C334 + C105 333 VR304 L303 + C122 DC.OFFSET TC301 + C127 MOD.LEVEL J 0 ADJ TC301 Q109 IC301 L304 CORD www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 7 CD-P75FM 5 6 7 8 A B C D 5 6 7 8 SIDE A A F VR304 L303 + 2 + C127 MOD.LEVEL + C331 J101 D117 + C348 + C325 PILOT.LEVEL 224 VR303 + C128 X102 7.2MHz X301 J102 333 VR301 DC.OFFSET 38KHz + C126 IC105 J106 J103 J107 + C322 + C317 J108 + C125 + C318 J105 J301 L301 + C307 J302 J104 J303 IC301 J109 + C303 L302 J110 CN102 J112 + C305 + C321 + C116 D113 + C117 + C306 J111 J114 J113 + C308 Q109 CKS2482 + C304 CN103 CZK2048 + C349 D308 D307 + C350 CD-P75FM CD-P75FM CD-P75FM 7-A X101 + C124 S101 RESET 6.2914 MHz + C115 IP BUS INPUT B CN201 B www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 8 CD-P75FM ANT JA CK C102 L101 R330 C341 Q115 CN101 B.OUT R332 RY101 C340 C129 L304 ACC C337 Q303 C101 C346 D101 B.IN C338 R331 C345 R110 R142 R104 D118 D104 R337 R329 R339 R102 GND Q305 C344 ANT PLUG Q304 D103 C104 R338 D303 R111 C339 R101 C343 Q102 R336 R333 Q101 C109 7.1V D306 D105 R334 L306 D102 R106 R335 C336 VF C110 R328 VR305 R327 R326 R105 L305 R103 C103 C334 C106 C105 R325 8.4V Q103 D302 R324 R107 C347 COMP C333 C335 C328 R323 R137 C342 R318 R317 C332 TC301 VR304 R141 Q114 R136 C123 R320 Q113 R319 Q110 Q111 L303 R140 C122 1 R322 D115 R135 C121 C127 C329 R321 IC303 D305 C331 C327 J101 R354 D114 D117 X1 Q303 Q304 Q305 IC302 IC304 Q115 Q107 Q108 IC303 IC103 Q110 Q111 Q112 Q116 IC105 Q101 Q102 Q114 IC104 Q306 IC101 IC102 Q106 Q113 Q103 Q105 A 1 2 3 4 B C D 1 2 3 4 A F HAIDEAWAY UNIT A www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 9 CD-P75FM 5 C121 C127 C329 R321 C303 D305 C331 C327 J101 4 D114 D117 C330 R340 D304 C348 IC104 C325 VR303 C128 C120 X102 R351 R350 R353 X301 C324 J102 1 MPX R352 IC302 R349 R316 C119 C326 VR301 R144 C126 C323 IC105 R315 R313 J106 J103 1 R347 J107 C322 C317 C313 C319 C320 L 5V J108 C125 C318 C315 R307 1 J105 R348 J301 R314 R356 C309 L301 R355 R114 Q105 C307 R346 C316 R345 J302 IC304 J104 C314 C311 R312 R309 J303 IC301 1 R311 R R113 J109 R301 C303 B.SEN L302 R310 C312 R303 J1 10 R308 C310 A.SEN J112 R305 C305 C321 R306 Q108 C116 SW+B D113 C117 L- R304 R- R134 R+ R133 C118 R302 R132 L+ C306 J111 J114 J113 GND D106 C308 C302 Q107 7.8V Q109 TS1 TS0 C301 AsenB TCK DPDT R126 R143 C304 R343 R131 C111 R129 10 1 R341 BUS- R 116 VDD R342 BUS+ D112 R125 C349 KYDT R115 R139 R118 R117 Q306 R130 R109 /J--/UC./EW D308 D307 D111 C350 C113 R128 R127 Q116 Q112 R112 R108 D109 IC103 30 70 TEST X101 C112 IC101 C124 C 131 C130 R121 40 1 R138 R123 D M R122 D110 D116 S101 R119 Q106 C114 R124 C115 60 50 R120 IC102 RESET 5 6 7 8 A B C D 5 6 7 8 SIDE B A www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 10 CD-P75FM Unit Number :CZX3224(UC) :CZX3227(EW) Unit Name :Hideaway Unit MISCELLANEOUS IC 101 IC PA0051AM IC 102 IC S-80731AN-DV IC 103 IC PD4953A IC 104 IC BU2616F IC 105 IC HA178L05 IC 301 IC TA2050S IC 302 IC BA1405F IC 303 IC UPC4570G IC 304 IC TC4066BF Q 101 Transistor 2SD1858 Q 102 Transistor 2SC2412K Q 103 Transistor 2SC2412K Q 105 Transistor 2SB1197K Q 106 Transistor DTA114EK Q 107 Transistor DTC114EK Q 108 Transistor 2SB1197K Q 109 Transistor 2SD2395 Q 110 Transistor 2SC2412KLN Q 111 Transistor 2SC2412KLN Q 112 Transistor DTC114EK Q 113 Transistor 2SB1197K Q 114 Transistor 2SD1781K Q 115 Transistor DTC114GK Q 116 Transistor DTC114EK Q 303 Transistor 2SC2413K Q 304 Transistor 2SC2413K Q 305 Transistor 2SC2413K Q 306 Transistor 2SD1781K D 101 Diode ERA15-02 D 102 Diode ERA15-02 D 103 Diode HZS6L(B1) D 104 Diode HZS7(C1) D 105 Diode HZS7(C1) D 106 Diode 1SS355 D 109 Diode DAP202K D 110 Diode 1SS355 D 111 Diode DA204K D 112 Diode DA204K D 113 Diode HZS9(B2) D 114 Diode 1SS355 D 115 Diode 1SS355 D 116 Diode 1SS355 D 117 Diode HZS9L(C2) D 118 Diode 1SS133 D 302 Diode 1SS355 D 303 Diode 1SS133 D 304 Diode RB421D D 305 Diode RB421D D 306 Diode KV1440 D 307 Diode HZS9(B2) D 308 Diode HZS9L(C2) L 101 Choke Coil 1mH CTH1122 L 301 Inductor CZT2015 L 302 Inductor CZT2015 L 303 Inductor CZT2004 L 304 Coil CZT2016 L 305 Ferri-Inductor LAU2R2M L 306 Inductor LCTBR68K2125 TC 301 CZC2031 RY 101 Relay CZS2026 X 101 6.29MHz CSS1303 X 102 Crystal Resonator 7.200MHz CSS1030 X 301 38kHz CZS2030 S 101 Switch(RESET) CZS2032 VR 301 Volume 33kΩ(B) CZC2050 VR 303 Volume 220kΩ(B) CZC2051 VR 304 Volume 33kΩ(B) CZC2050 VR 305 Volume 1kΩ(B) CZC2053 RESISTORS R 101 RS1/10S123J R 102 RS1/10S103J R 103 RS1/10S103J R 104 RS1/10S473J R 105 RS1/10S473J R 106 RS1/10S682J R 107 RS1/10S682J R 108 RS1/10S473J R 109 RS1/10S104J R 110 RD1/4PM103J R 111 RD1/2PM102J R 112 RS1/10S0R0J R 113 RS1/10S222J R 114 RS1/10S472J R 115 RS1/10S332J R 116 RS1/10S620J R 117 RS1/10S101J R 118 RS1/10S101J R 119 RS1/10S102J R 120 RS1/10S102J R 121 RS1/10S473J R 122 RS1/10S473J R 123 RS1/10S124J R 124 RS1/10S103J R 126 RS1/10S562J R 127 RS1/10S473J R 128 RS1/10S222J R 129 RS1/10S222J R 130 RS1/10S222J R 131 RS1/10S222J R 132 RS1/10S562J R 133 RS1/10S472J R 134 RS1/10S222J R 135 RS1/10S103J R 136 RS1/10S122J 5. ELECTRICAL PARTS LIST NOTE: - Parts whose parts numbers are omitted are subject to being not supplied. - The part numbers shown below indicate chip components. Chip Resistor RS1/_S___J,RS1/__S___J Chip Capacitor (except for CQS.....) CKS....., CCS....., CSZS..... =====Circuit Symbol and No.===Part Name Part No. --- ------ ------------------------------------------ ------------------------- =====Circuit Symbol and No.===Part Name Part No. --- ------ ------------------------------------------ ------------------------- A F www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 11 CD-P75FM R 137 RS1/10S103J R 138 RS1/10S220J R 139 RS1/10S562J R 140 RS1/10S103J R 141 RS1/10S272J R 142 RS1/10S222J R 143 RS1/10S104J R 144 RS1/10S0R0J R 301 RS1/10S181J R 302 RS1/10S181J R 303 RS1/10S223J R 304 RS1/10S223J R 305 RS1/10S102J R 306 RS1/10S102J R 307 RS1/10S202J R 308 RS1/10S202J R 309 RS1/10S133J R 310 RS1/10S133J R 311 RS1/10S752J R 312 RS1/10S752J R 313 (UC) RS1/10S563J R 313 (EW) RS1/10S393J R 314 (UC) RS1/10S563J R 314 (EW) RS1/10S393J R 315 RS1/10S332J R 316 RS1/10S152J R 317 RS1/10S103J R 318 RS1/10S103J R 319 RS1/10S104J R 320 RS1/10S104J R 321 RS1/10S563J R 322 (UC) RS1/10S103J R 322 (EW) RS1/10S183J R 323 RS1/10S473J R 324 RS1/10S103J R 325 RS1/10S103J R 326 RS1/10S822J R 327 RS1/10S332J R 328 RS1/10S103J R 329 RS1/10S103J R 330 RS1/10S332J R 331 RS1/10S103J R 332 RS1/10S560J R 333 RS1/10S104J R 334 RS1/10S222J R 335 RS1/10S101J R 336 RS1/10S474J R 337 RS1/10S154J R 338 RS1/10S152J R 339 RS1/10S122J R 340 RS1/10S683J R 341 RS1/10S102J R 342 RS1/10S222J R 343 RS1/10S0R0J R 345 RS1/10S273J R 346 RS1/10S273J R 347 RS1/10S681J R 348 RS1/10S681J R 349 RS1/10S392J R 350 RS1/10S392J R 351 RS1/10S392J R 352 RS1/10S182J R 353 RS1/10S392J R 354 RS1/10S103J R 355 RS1/10S752J R 356 RS1/10S752J CAPACITORS C 101 EMI Filter CCG1006 C 102 1000µF/16V CZC2055 C 103 2200µF/16V CCH1001 C 104 CEAS330M10 C 105 CEAS101M10 C 106 CKSQYB223K50 C 109 CKSQYB104K25 C 110 CEAS1R0M50 C 111 CKSQYB104K25 C 112 CKSQYB102K50 C 113 CKSQYB102K50 C 114 CKSQYB103K50 C 115 CEAS2R2M50 C 116 CEAS100M16 C 117 CEAS100M16 C 118 CKSQYB223K50 C 119 CCSQCH270J50 C 120 CCSQCH270J50 C 121 CKSQYB103K50 C 122 CEJA330M10 C 123 CKSQYB473K50 C 124 CEAS330M10 C 125 CEAS101M10 C 126 CEAS101M16 C 127 CEAS330M10 C 128 CEAS101M10 C 129 CEJAR22M50 C 130 CCSQCH240J50 C 131 CCSQCH240J50 C 301 CKSQYB104K25 C 302 CKSQYB104K25 C 303 CEJA1R0M50 C 304 CEJA1R0M50 C 305 CEJA1R0M50 C 306 CEJA1R0M50 C 307 CEJA100M16 C 308 CEJA100M16 C 309 CKSQYB472K50 C 310 CKSQYB472K50 C 311 CKSQYB392K50 C 312 CKSQYB392K50 C 313 (UC) CKSQYB152K50 C 313 (EW) CKSQYB122K50 C 314 (UC) CKSQYB152K50 C 314 (EW) CKSQYB122K50 C 315 CKSQYB222K50 C 316 CKSQYB222K50 C 317 CEJAR22M50 C 318 CEJAR22M50 C 319 CKSQYB471K50 C 320 CKSQYB471K50 C 321 CEJA220M10 C 322 CEJA100M16 C 323 CKSQYB103K50 C 324 CCSQCH100D50 C 325 CEJA100M16 C 326 CKSQYB103K50 C 327 CCSQCH221J50 C 328 CKSQYB104K25 C 329 CCSQCH150J50 C 330 CKSYB105K16 C 331 CEJA100M16 C 332 CKSQYB182K50 C 333 CCSQCH331J50 C 334 CEJA100M16 =====Circuit Symbol and No.===Part Name Part No. --- ------ ------------------------------------------ ------------------------- =====Circuit Symbol and No.===Part Name Part No. --- ------ ------------------------------------------ ------------------------- www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com GENERAL INFORMATION IC C 335 CKSQYB681K50 C 336 CKSYB105K16 C 337 CCSQCH200J50 C 338 CCSQCH100D50 C 339 CCSQCK1R0C50 C 340 CCSQCH330J50 C 341 CCSQCH180J50 C 342 CKSQYB103K50 C 343 CCSQCK1R0C50 C 344 CCSQCH3R0C50 C 345 CKSQYB103K50 C 346 CKSQYB103K50 C 347 CKSQYB103K50 C 348 CEJA1R0M50 C 349 CEAS471M10 C 350 CEAS470M16 12 CD-P75FM =====Circuit Symbol and No.===Part Name Part No. --- ------ ------------------------------------------ ------------------------- 20 21 40 41 60 61 80 1 *PD4953A IC's marked by* are MOS type. Be careful in handling them because they are very liable to be damaged by electrostatic induction. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 13 CD-P75FM - Pin Functions (PD4953A) Pin No. Pin Name I/O Format Function and Operation 1 MODEL I Model select input 2,3 NC Not used 4 AVSS A/D GND 5,6 NC Not used 7 AVREF1 VSS 8 KYDT I Data input 9 DPDT O C Data output 10 SWVDD O C Grille power supply control output 11 PREN O C Pre-emphasis output 12 PLDO O C PLL data output 13 PLCK O C PLL clock output 14 PLCE O C PLL CE output 15 NC Not used 16 TSI I Test program serial input 17 TSO O C Test program serial output 18 tck I Test program serial clock 19-32 NC Not used 33 VSS GND 34-41 NC Not used 42 busmute O C BUS mute output 43-45 NC Not used 46 mute O C Mute output 47-53 NC Not used 54 SYSPW O C System power supply control output 55 ASENBO O C Slave power supply control output 56 TX O C IP BUS data output 57 RX I IP BUS data input 58 ippw O C Power supply control output for IP BUS interface IC 59 NC Not used 60 reset Reset 61 NC Not used 62 bsens I Back up power sense input 63 asens I ACC power sense input 64-67 NC Not used 68 VDD Power supply 69 X2 Crystal oscillator connection pin 70 X1 Crystal oscillator connection pin 71 IC GND 72 NC Not used 73 TESTIN I Test program mode input 74 AVDD Positive power supply terminal for analog circuit 75 AVREF0 GND 76-80 NC Not used www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com
