ORDER NO. PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A. PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936 PIONEER CORPORATION 2005 AVIC-D1/UC CRT3466 DOUBLE-DIN DVD NAVIGATION SYSTEM AVIC-D1/UC This service manual should be used together with the following manual(s): Model No. Order No. Mech.Module Remarks CX-3016 CRT3056 MS3 DVD Mech. Module:Circuit Description, Mech. Description, Disassembly CX-3158 CRT3394 S10.1AAC CD Mech. Module:Circuit Description, Mech. Description, Disassembly For details, refer to "Important Check Points for Good Servicing". K-ZZW. APR. 2005 Printed in Japan This product has the unit part number as below. Unit Part No. CPN1951 Description Navigation Unit *) The unit part numbers listed above are not for the service components. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 2 1 2 3 4 1 2 3 4 C D F A B E SAFETY INFORMATION CAUTION This service manual is intended for qualified service technicians; it is not meant for the casual do-it-yourselfer. Qualified technicians have the necessary test equipment and tools, and have been trained to properly and safely repair performed can adversely affect the and reliability of the product and may void the . If you are not qualified to the repair of this product properly and , you should not risk trying to do so WARNING WARNING W This product contains lead in solder and certain electrical parts contain chemicals which are known to the state of Health & Safety Code Section 25249.6 - Proposition 65 This product contains mercury. Disposal of this material may be regulated due to environmental considerations. For disposal or recycling information, please contact your local authorities or the Electronics Industries Alliance: www.eiae.org. DVD MECHANISM MODULE section precaution 1. EJECT LOCK MODE for DVD mechanism In order to enter "EJECT LOCK" mode, reset start while pressing the "AV" and "INFO" keys together. Pressing the "AV" and "INFO" keys until monitor backlight is turned on. In order to exit "EJECT LOCK" mode, follow the same steps to enter this mode. 2. Before disassembling the unit, be sure to turn off the power. Unplugging and plugging the connectors during power-on mode may damage the ICs inside the unit. 3. To protect the pickup unit from electrostatic discharge during servicing, take an appropriate treatment (shorting-solder) by referring to "the DISASSEMBLY" . 4. After replacing the pickup unit, be sure to skew adjustment. 5. During disassembly, be sure to turn the power off since an internal IC might be destroyed when a connector is plugged or unplugged. CD MECHANISM MODULE section precaution 1. Before disassembling the unit, be sure to turn off the power. Unplugging and plugging the connectors during power-on mode may damage the ICs inside the unit. 2. To protect the pickup unit from electrostatic discharge during servicing, take an appropriate treatment (shorting-solder) by referring to "the DISASSEMBLY". 3. After replacing the pickup unit, be sure to check the grating. - Service Precautions 1. You should conform to the regulations governing the product (safety, radio and noise, and other regulations), and should keep the safety during servicing by following the safety instructions described in this manual. is a trademark of DVD Format/Logo Licensing Corporation. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 3 5 6 7 8 5 6 7 8 C D F A B E [Important Check Points for Good Servicing] In this manual, procedures that must be performed during repairs are marked with the below symbol. Please be sure to confirm and follow these procedures. 1. Product safety Please conform to product regulations (such as safety and radiation regulations), and maintain a safe servicing environment by following the safety instructions described in this manual. 1 Use specified parts for repair. Use genuine parts. Be sure to use important parts for safety. 2 Do not perform modifications without proper instructions. Please follow the specified safety methods when modification(addition/change of parts) is required due to interferences such as radio/TV interference and foreign noise. 3 Make sure the soldering of repaired locations is properly performed. When you solder while repairing, please be sure that there are no cold solder and other debris. Soldering should be finished with the proper quantity. (Refer to the example) 4 Make sure the screws are tightly fastened. Please be sure that all screws are fastened, and that there are no loose screws. 5 Make sure each connectors are correctly inserted. Please be sure that all connectors are inserted, and that there are no imperfect insertion. 6 Make sure the wiring cables are set to their original state. Please replace the wiring and cables to the original state after repairs. In addition, be sure that there are no pinched wires, etc. 7 Make sure screws and soldering scraps do not remain inside the product. Please check that neither solder debris nor screws remain inside the product. 8 There should be no semi-broken wires, scratches, melting, etc. on the coating of the power cord. Damaged power cords may lead to fire accidents, so please be sure that there are no damages. If you find a damaged power cord, please exchange it with a suitable one. 9 There should be no spark traces or similar marks on the power plug. When spark traces or similar marks are found on the power supply plug, please check the connection and advise on secure connections and suitable usage. Please exchange the power cord if necessary. 0 Safe environment should be secured during servicing. When you perform repairs, please pay attention to static electricity, furniture, household articles, etc. in order to prevent injuries. Please pay attention to your surroundings and repair safely. 2. Adjustments To keep the original performance of the products, optimum adjustments and confirmation of characteristics within specification. Adjustments should be performed in accordance with the procedures/instructions described in this manual. 4. Cleaning For parts that require cleaning, such as optical pickups, tape deck heads, lenses and mirrors used in projection monitors, proper cleaning should be performed to restore their performances. 3. Lubricants, Glues, and Replacement parts Use grease and adhesives that are equal to the specified substance. Make sure the proper amount is applied. 5. Shipping mode and Shipping screws To protect products from damages or failures during transit, the shipping mode should be set or the shipping screws should be installed before shipment. Please be sure to follow this method especially if it is specified in this manual. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 4 1 2 3 4 1 2 3 4 C D F A B E CONTENTS SAFETY INFORMATION..................................................................................................................................... 2 1. SPECIFICATIONS ............................................................................................................................................ 5 2. EXPLODED VIEWS AND PARTS LIST ............................................................................................................ 8 2.1 PACKING ................................................................................................................................................... 8 2.2 EXTERIOR (1) ......................................................................................................................................... 10 2.3 EXTERIOR (2) ......................................................................................................................................... 12 2.4 EXTERIOR (3) ......................................................................................................................................... 14 2.5 DVD MECHANISM MODULE(MS3)......................................................................................................... 16 2.6 CD MECHANISM MODULE(S10.1AACA)............................................................................................... 18 3. BLOCK DIAGRAM AND SCHEMATIC DIAGRAM.......................................................................................... 20 3.1 BLOCK DIAGRAM ................................................................................................................................... 20 3.2 OVERALL CONNECTION DIAGRAM...................................................................................................... 32 3.3 CC UNIT (P/S) ......................................................................................................................................... 34 3.4 CC UNIT (CPU, ASIC, SDRAM)(GUIDE PAGE) ...................................................................................... 36 3.5 CC UNIT (GRAPHIC)(GUIDE PAGE) ...................................................................................................... 42 3.6 CC UNIT (ROM, SRAM, BUS-BUFFER) ................................................................................................. 48 3.7 CC UNIT (MAIN, CC CORE I/F) .............................................................................................................. 50 3.8 CC UNIT (GPS, SENSOR, VIDEO, I/F) ................................................................................................... 52 3.9 GPS UNIT (GUIDE PAGE)....................................................................................................................... 58 3.10 DVD CORE UNIT(MS3R)(GUIDE PAGE) .............................................................................................. 64 3.11 COMPOUND UNIT(A) AND COMPOUND UNIT(B) .............................................................................. 72 3.12 PU UNIT(REFERENCE) ........................................................................................................................ 73 3.13 CD MECHANISM MODULE(GUIDE PAGE) .......................................................................................... 74 3.14 SYSTEM UNIT (AUDIO) ........................................................................................................................ 84 3.15 SYSTEM UNIT (SYSCOM, VIDEO, I/F)(GUIDE PAGE)......................................................................... 86 3.16 SYSTEM UNIT (P/S).............................................................................................................................. 92 3.17 MONITOR PCB (GUIDE PAGE)............................................................................................................. 94 3.18 KEYBOARD PCB................................................................................................................................. 102 3.19 PANEL PCB ......................................................................................................................................... 104 3.20 CONNECTOR UNIT............................................................................................................................. 106 3.21 MAIN PCB UNIT .................................................................................................................................. 108 4. PCB CONNECTION DIAGRAM ................................................................................................................... 110 4.1 CC UNIT................................................................................................................................................. 110 4.2 GPS UNIT .............................................................................................................................................. 114 4.3 DVD CORE UNIT(MS3R)....................................................................................................................... 116 4.4 COMPOUND UNIT(A) AND COMPOUND UNIT(B) .............................................................................. 120 4.5 CD CORE UNIT(S10.1) ......................................................................................................................... 122 4.6 SYSTEM UNIT....................................................................................................................................... 124 4.7 MONITOR PCB...................................................................................................................................... 128 4.8 KEYBOARD PCB................................................................................................................................... 132 4.9 PANEL PCB ........................................................................................................................................... 134 4.10 CONNECTOR UNIT............................................................................................................................. 136 4.11 MAIN PCB UNIT .................................................................................................................................. 138 5. ELECTRICAL PARTS LIST .......................................................................................................................... 140 6. ADJUSTMENT ............................................................................................................................................. 166 6.1 JIG CONNECTION DIAGRAM............................................................................................................... 166 6.2 DVD ADJUSTMENT............................................................................................................................... 167 6.3 CD ADJUSTMENT................................................................................................................................. 172 6.4 CHECKING THE GRATING AFTER CHANGING THE PICKUP UNIT .................................................. 174 6.5 ERROR MODE ...................................................................................................................................... 176 6.6 MONITOR PCB ADJUSTMENT............................................................................................................. 177 6.7 TEST MODE .......................................................................................................................................... 186 6.8 USING THE TEST DISC ........................................................................................................................ 209 7. GENERAL INFORMATION........................................................................................................................... 221 7.1 DIAGNOSIS ........................................................................................................................................... 221 7.1.1 DISASSEMBLY ................................................................................................................................... 221 7.1.2 PCB LOCATIONS ............................................................................................................................... 231 7.1.3 CONNECTOR FUNCTION DESCRIPTION........................................................................................ 232 7.2 IC ........................................................................................................................................................... 233 7.3 EXPLANATION ...................................................................................................................................... 258 7.3.1 MECHANISM DESCRIPTIONS .......................................................................................................... 258 7.3.2 OPERATIONAL FLOW CHART .......................................................................................................... 264 8. OPERATIONS .............................................................................................................................................. 266 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 5 5 6 7 8 5 6 7 8 C D F A B E 1. SPECIFICATIONS General Rated power source............14.4 V DC (10.8 - 15.1 V allowable) Grounding system...............Negative type Max. current consumption ...................................10.0 A Navigation unit: Dimensions (W x H x D): DIN Chassis.................178 x 100 x 160 mm (7 x 3-7/8 x 6-1/4 in.) Nose......................191 x 114 x 5 mm (7-1/2 x 4-1/2 x 1/4 in.) D Chassis.................178 x 100 x 165 mm (7 x 3-7/8 x 6-1/2 in.) Nose......................171 x 93 x 24 mm (6-3/4 x 3-5/8 x 1 in.) Weight ..........................2.9 kg (6.4 lbs) Navigation GPS Receiver: System..........................L1, C/Acode GPS SPS (Standard Positioning Service) Reception system........8-channel multi-channel reception system Reception frequency...1,575.42 MHz Sensitivity.....................–130 dBm Position update frequency ...................................Approx. once per second GPS antenna: Antenna........................Micro strip flat antenna/ right-handed helical polari- zation Antenna cable.............. 5.0 m (16 ft. 5 in.) Dimensions (W x H x D) ...................................33 x 13 x 36 mm (1-1/4 x 1/2 x 1-3/8 in.) Weight ..........................105 g(0.23 lbs) Display Screen size/aspect ratio.....6.5 inch wide/16:9 (effective display area: 144 x 76 mm) Pixels.................................... 336,960 (1,440 x 234) Type...................................... TFT active matrix, transmis- sive type Color system........................ NTSC Operating temperature range ........................................... –14 – +122 °F Storage temperature range ........................................... –4 – +176 °F Angle adjustment.................. 0 – 21° (initial settings: 0°) Audio Continuous power output is 22 W per channel minimum into 4 ohms, both channels driven 50 to 15,000 Hz with no more than 5% THD. Maximum power output ...... 50 W x 4 50 W x 2 ch/4 Ω + 70 W x 1 ch/2 Ω (for subwoofer) Load impedance...................4 Ω (4 – 8 Ω [2 Ω for 1 ch] allowable) Preout max output level/output impedance ............................................ 2.0 V/100 ohm Equalizer (3-Band Parametric Equalizer): Low Frequency.............. 40/80/100/160 Hz Q Factor..................0.35/0.59/0.95/1.15 (+6 dB when boosted) Gain....................... ±12dB Mid Frequency..............200/500/1k/2k Hz Q Factor..................0.35/0.59/0.95/1.15 (+6 dB when boosted) Gain....................... ±12dB High Frequency............. 3.15k/8k/10k/12.5k Hz Q Factor................. 0.35/0.59/0.95/1.15 (+6 dB when boosted) Gain.......................±12dB Loudness contour Low................................+3.5 dB (100 Hz), +3 dB (10 kHz) Mid.................................+10 dB (100 Hz), +6.5 dB (10 kHz) High ....................... +11 dB (100 Hz), +11 dB (10 kHz) (volume: –30 dB) HPF: Frequency..................... 50/80/125 Hz Slope.............................. –12 dB/oct Subwoofer: Frequency..................... 50/80/125 Hz Slope..............................–18 dB/oct Gain...............................±12dB Phase............................ Normal/Reverse CD Drive System...................................Compact disc audio system Usable discs..........................Compact disc Signal format: Sampling frequency.....44.1 kHz Number of quantization bits ....................................16; linear Frequency characteristics... 5 – 20,000 Hz (±1 dB) Signal-to-noise ratio............. 94 dB (1 kHz) (IHF-A net- work) Dynamic range.....................92 dB (1 kHz) Number of channels............ 2 (stereo) MP3 decoding format..........MPEG-1 & 2 Audio Layer 3 WMA decoding format ........Ver 7, 7.1, 8, 9 (2ch audio) Wave signal format..............Linear-PCM, MS ADPCM FM tuner Frequency range..................87.9 – 107.9 MHz Backup current ................... 3.0 mA or less www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 6 1 2 3 4 1 2 3 4 C D F A B E Usable sensitivity.................. 8 dBf (0.7 µV/75 Ω, mono, S/ N: 30 dB) 50 dB quieting sensitivity.......10 dBf (0.9 µV/75 Ω, mono) Signal-to-noise ratio.............. 75 dB (IHF-A network) Distortion.............................. 0.3 % (at 65 dBf, 1 kHz, stereo) 0.1 % (at 65 dBf, 1 kHz, mono) Frequency response.............. 30 – 15,000 Hz (±3 dB) Stereo separation..................45 dB (at 65 dBf, 1 kHz) Selectivity..............................80 dB (±200 kHz) Three-signal intermodulation (desired signal level) .......................................... 30 dBf (two undesired signal level: 100 dBf) AM tuner Frequency range..................530 – 1,710 kHz (10 kHz) Usable sensitivity.................18 µV (S/N: 20 dB) Signal-to-noise ratio............. 65 dB (IHF-A network) Note: • Specifications and the design are subject to possible modifications without notice due to improvements. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 7 5 6 7 8 5 6 7 8 C D F A B E www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 8 1 2 3 4 1 2 3 4 C D F A B E 2. EXPLODED VIEWS AND PARTS LIST 2.1 PACKING NOTES : • Parts marked by " * " are generally unavailable because they are not in our Master Spare Parts List. • The > mark found on some component parts indicates the importance of the safety factor of the part. Therefore, when replacing, be sure to use parts of identical designation. • Screw adjacent to mark on the product are used for disassembly. • For the applying amount of lobricants or glue, follow the instructions in this manual. (In the case of no amount instructions,apply as you think it appropriate.) " www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 9 5 6 7 8 5 6 7 8 C D F A B E PACKING SECTION PARTS LIST Mark No. Description Part No. * 1-1 Card ARY1048 1-2 Caution Card CRP1310 * 1-3 Registration Card CRY1238 1-4 Polyethylene Bag CEG1116 1-5 Owner's Manual/POC/FRE CRB2091 1-6 Owner's Manual/POC/FRE CRB2090 2-1 Owner's Manual CRB2088 2-2 Owner's Manual CRB2089 2-3 Installation Manual CRD3983 2-4 Connector CKX1049 2-5 Polyethylene Bag CEG1116 3 Cover CEG1359 4 Carton CHG5523 5 Contain Box CHL5523 6 Protector CHP2273 7 Protector CHP3006 8 Protector CHP3007 9 Protector CHP3045 10 Protector CHP3046 11 Cord CDE5044 12 Cord CDE6825 13 Cord Assy CDE7838 14 Cord Assy CDE7839 15 Screw Assy CEA3797 16 Screw BMZ50P060FTC * 17 Polyethylene Bag CEG-127 18 Screw CMZ50P060FTC 19 Sub Carton CHA3298 20 Panel CNS8298 21 GPS Antenna Assy CXC4864 22 Water Proof Pad CZN5442 23 Sheet CZN7008 24 DVD-ROM CPJ1167 - Owner's Manual, Installation Manual Part No. CRB2088, CRB2089 CRB2090, CRB2091 CRD3983 Language English French English, French - Be careful when ordering parts, as the following unit of this mainframe is described on several pages. MONI_PANEL Unit CWM9920 MONITOR PCB KEYBOARD PCB PANEL PCB Page 15 No. 18(1/2) Page 15 No. 18(2/2) Page 11 No. 58 Description Part No. PCB name Reference page and No. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 10 1 2 3 4 1 2 3 4 C D F A B E 2.2 EXTERIOR (1) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 11 5 6 7 8 5 6 7 8 C D F A B E EXTERIOR (1) SECTION PARTS LIST Mark No. Description Part No. 1 Screw BMZ26P030FTB 2 Screw BMZ26P040FTC 3 Screw BMZ26P060FTB 4 Screw BMZ26P140FTC 5 Screw(M2x3) CBA1527 6 Screw(M3x10) CBA1637 7 Screw(M2x2) CBA1735 8 Screw(M2x3) CBA1877 9 Spring CBH2888 10 Cord Assy CDE7908 11 FFC CDE8006 12 FFC CDE8007 13 Cord Assy CDE8008 14 Screw CMZ50P060FTC 15 Case CNB3109 16 Cover CND1509 17 Holder CND2682 18 Holder CND2683 19 Shield CND2775 20 Holder CND2794 21 Bracket CND2795 22 Insulator CNM8550 23 Insulator CNM9442 24 Gasket CNM9593 25 Cushion CNM9653 26 Shield CNM9656 27 Flexible PCB CNP8450 28 Heat Sink CNR1785 29 Cover CNS8290 30 System Unit CWM9918 31 Screw BMZ26P050FTC 32 FM/AM Tuner Unit CWE1646 33 Holder CND1054 34 Terminal(CN1302) CKF1064 35 Terminal(CN1303) CKF1064 36 Terminal(CN1304) CKF1064 37 Terminal(CN1305) CKF1064 38 Terminal(CN4301) CKF1064 39 Connector(CN1801) CKM1438 40 Connector(CN1401) CKM1460 41 Jack(CN1450) CKN1036 42 Connector(CN1803) CKS4822 43 Connector(CN1301) CKS4919 44 Connector(CN1651) CKS4980 45 Connector(CN1701) CKS5110 46 Connector(CN1802) CKS5270 47 Antenna Jack(CN4300) CKX1056 48 Holder CND2667 49 Holder CND2668 50 Holder CND2669 51 Holder CND2670 52 Holder CND2671 53 Holder CND2685 54 Button(CD EJECT) CAC9119 55 Button(DVD EJECT) CAC9120 56 Panel Unit CXC4435 57 Screw IMS26P040FTC 58 MONI_PANEL Unit CWM9920 59 Connector(CN5901) CKS4825 60 Chassis Unit CXC4333 61 CD Mechanism Module(S10.1AACA) CXK5668 62 DVD Mechanism Module(MS3) CXK6333 63 Fan Motor CXM1320 64 Screw ISS26P055FTC 65 Tape CNM9890 66 IC(IC4200) PAL007B 67 Transistor(Q1900, 1902) 2SB1185 68 Transistor(Q1922) 2SD2396 Mark No. Description Part No. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 12 1 2 3 4 1 2 3 4 C D F A B E 2.3 EXTERIOR (2) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 13 5 6 7 8 5 6 7 8 C D F A B E EXTERIOR (2) SECTION PARTS LIST Mark No. Description Part No. 1 Drive Unit CXC4423 2 Screw(M2x6) CBA1399 3 Screw(M2x1.5) CBA1615 4 Screw(M2x2) CBA1771 5 Spring CZB3092 6 Spring CZB3093 7 Screw CZB3097 8 Washer CZB5003 9 Shaft CZL3010 10 Gear CZN7011 11 Gear CZN7012 12 Gear CZN7013 13 Rack CZN7014 14 Holder CZN7015 15 Roller CZN7052 16 Holder CZN7042 17 Holder CZN7043 18 Sheet CZN7044 19 Main PCB Unit CZW3097 20 Screw BMZ26P050FTC 21 Connector(CN2) CKS4600 22 Heat Sink CND1228 23 Connector(CN1) CZK3071 24 Transistor(Q1) 2SB1185 25 Bracket Unit CZX5101 26 Motor Unit(FLAP)(M10) CZX5102 27 Chassis Unit CZX5127 28 Frame Unit CZX5160 29 Screw JFZ20P020FTC 30 Washer YE15S 31 CC Unit CWM9919 32 Terminal(CN100) CKF1064 33 Terminal(CN601) CKF1064 34 Terminal(CN602) CKF1064 35 Terminal(CN802) CKF1064 36 Connector(CN701) CKS3805 37 Connector(CN702) CKS3991 38 Connector(CN551) CKS4065 39 Connector(CN651) CKS4473 40 Connector(CN801) CKS4674 41 Connector(CN605) CKS5110 42 Holder CND2672 43 Shield CND2675 44 Shield CND2676 45 Shield CND2679 46 Shield CND2680 47 Sheet CNM6903 48 Insulator CNM9436 49 Insulator CNM9437 50 Insulator CNM9438 51 Insulator CNM9439 52 GPS Unit CWX3141 53 Connector(CN461) CKS4280 54 Connector(CN504) CKS4432 55 Shield CNC9191 56 Shield CNC9192 57 Holder CND1535 58 Connector(CN2) DKN1236 59 Connector Unit CWM9921 60 Terminal(CN2807) CKF1064 61 Connector(CN2802) CKS3414 62 Connector(CN2801) CKS4590 63 Connector(CN2806) CKS4600 64 Connector(CN2804) CKS5209 65 Holder(CN58) CNC2218 66 Holder CND2673 67 FFC CDE7864 68 FFC CDE8005 69 Screw ISS26P055FTC 70 ••••• 71 Cushion CNM9416 Mark No. Description Part No. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 14 1 2 3 4 1 2 3 4 C D F A B E 2.4 EXTERIOR (3) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 15 5 6 7 8 5 6 7 8 C D F A B E EXTERIOR (3) SECTION PARTS LIST Mark No. Description Part No. 1 Button(MAP, AV) CAC9112 2 Button(OPEN, ANGLE) CAC9114 3 Button(TRFC) CAC9115 4 Button(P.ADJ, MEMO) CAC9118 5 Button(SRC) CAC9429 6 Screw(M2x3) CBA1877 7 FFC CDE8003 8 Insulator CNM9475 9 Cover CNM9655 10 Guide CNV5169 11 Touch Panel CSX1085 12 Screw(M2x2) CBA1771 13 Holder CNC9991 14 Holder CND3075 15 Insulator CNM9567 16 Insulator CNM9803 17 Flexible PCB CNP8744 18 MONI_PANEL Unit CWM9920 19 Terminal(CN5003) CKF1064 20 Connector(CN5002) CKS3968 21 Connector(CN5801) CKS3991 22 Connector(CN5700) CKS4130 23 Connector(CN5331) CKS4428 24 Connector(CN5009) CKS4496 25 Connector(CN5007) CKS4675 26 Connector(CN5008) CKS5208 27 LCD Panel CWX3229 28 Screw PMB20P040FTC 29 Knob Unit CXC4417 30 Grille Unit CXC4434 31 Case Unit CXC4436 32 Sheet CNM9862 33 Button Unit(VOL) CXC4455 34 Button Unit(DEST, INFO) CXC4456 35 Cord CDE6825 36 Cap CNS1472 37 Resistor RS1/2PMF102J 38 Cord Assy CDE7838 39 Cap CNV6727 40 Cord Assy CDE7839 > 41 Fuse(10A) CEK1136 42 Cap CNS1472 43 Shield CNM9858 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 16 1 2 3 4 1 2 3 4 C D F A B E 2.5 DVD MECHANISM MODULE(MS3) C D E www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 17 5 6 7 8 5 6 7 8 C D F A B E DVD MECHANISM MODULE(MS3) SECTION PARTS LIST Mark No. Description Part No. 1 DVD Core Unit(MS3R) CWX3178 2 Connector(CN601) CKS5055 3 ••••• 4 Connector(CN1202) CKS5017 5 ••••• 6 ••••• 7 Connector(CN1101) CKS4842 8 Connector(CN1201) CKS5043 9 Screw BMZ20P020FTC 10 Screw(M2 x 3.5) CBA1571 11 Screw(M2 x 2.5) CBA1623 12 Washer CBF1038 13 Washer CBF1064 14 Spring CBH2586 15 Spring CBH2587 16 Spring CBH2588 17 Spring CBH2589 18 Spring CBH2590 19 Spring CBH2591 20 Spring CBH2592 21 Spring CBH2593 22 Spring CBH2594 23 Spring CBH2595 24 Spring CBH2596 25 Spring CBH2597 26 Spring CBH2598 27 Spring CBH2599 28 Spring CBH2600 29 Spring CBH2601 30 Spring CBH2602 31 Spring CBH2603 32 Spring CBH2604 33 Spring CBH2605 34 Spring CBH2711 35 Spring CBL1564 36 Pickup Unit(Service) CXX1640 37 Shaft CLA3881 38 Shaft CLA4206 39 Shaft CLA4207 40 Lever CNC9933 41 Holder CNC9939 42 Holder CND2251 43 Holder CNC9941 44 Frame CND2250 45 Sheet CNM6883 46 Sheet CNM8283 47 Sheet CNM8643 48 Lever CNV8076 49 Lever CNV7155 50 Cam CNV7156 51 Rack CNV7157 52 Clamper CNV7158 53 Arm CNV7159 54 Arm CNV7160 55 Arm CNV7161 56 Arm CNV7162 * 57 Arm CNV7163 58 Arm CNV7164 59 Roller CNV7165 60 Arm CNV7166 61 Guide CNV8093 62 Gear CNV7169 63 Gear CNV7170 64 Gear CNV7171 65 Gear(Black) CNV7172 66 Gear CNV7173 67 Gear CNV7174 68 Rack CNV7175 69 Gear CNV7176 70 Arm CNV8077 71 Lever CNV7178 72 Lever CNV7179 73 Screw IMS20P030FTC 74 Gear CNV7181 75 Holder CNV7183 76 Holder CNV7184 77 Guide CNV7745 78 Roller CNV7344 79 Damper CNV7470 80 Damper CNV7471 81 Collar CNV7645 82 Compound Unit(A) CWX3154 83 Screw(M1.4x1.4) CBA1787 84 Compound Unit(B) CWX3156 85 Washer YE20FTC 86 Chassis Unit CXC3629 87 Arm Unit CXB8681 88 Frame Unit CXB8683 89 Arm Unit CXC4701 90 Bracket Unit CXB8685 91 Motor Unit(LOADING)(M1) CXC4659 92 Motor Unit(CARRIAGE)(M2) CXC4314 93 Screw Unit CXB8689 94 Roller Unit CXB8690 95 Motor(SPINDLE)(M3) CXM1308 96 Screw JFZ20P018FTC 97 Photo-transistor(Q1299) CPT231SCTD 98 Switch(S1201) CSN1069 99 Spring Switch(S1204) CSN1070 100 Resistor(R1298) RS1/16S0R0J 101 Guide CNV7615 102 Screw(M1.7x1.2) CBA1572 103 Arm CNV7742 104 Arm CNV7743 105 Spring CBH2710 106 Spring CBL1643 107 Spring CBH2712 108 Pickup Unit(Service)(Screw) GXX1234 109 Screw Assy CXX1750 Mark No. Description Part No. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 18 1 2 3 4 1 2 3 4 C D F A B E 2.6 CD MECHANISM MODULE(S10.1AACA) A D H L M N O Q R A B C D E F G H I J K L M N O Q B 16 25 13 83 42 68 28 82 4 71 23 J K 38 23 59 87 86 5 13 34 5 5 13 44 5 C 52 53 36 4 73 29 51 18 64 76 50 10 72 75 49 77 67 27 78 60 90 48 8 17 46 6 60 11 89 43 70 14 31 65 85 66 85 31 35 14 74 85 1 2 3 R 91 12 33 61 63 21 79 57 58 62 80 13 4 86 I 45 28 7 24 47 P 41 20 40 69 39 30 P 19 56 F E 22 81 15 G 26 5 54 37 55 93 92 10 F 1GEM1024 2GEM1045 3GEM1035 1 1 1 1 1 1 1 1 2 2 2 2 1 1 1 1 1 2 2 1 3 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 19 5 6 7 8 5 6 7 8 C D F A B E CD MECHANISM MODULE(S10.1AACA) SECTION PARTS LIST Mark No. Description Part No. 1 CD Core Unit(S10.1) CWX3096 2 Connector(CN101) CKS4182 3 Connector(CN901) CKS4017 4 Screw BMZ20P035FTC 5 Screw BSZ20P040FTC 6 Screw(M2x4) CBA1362 7 Screw(M2x3) CBA1824 8 Screw(M2x3) CBA1825 9 ••••• 10 Washer CBF1038 11 Washer CBF1060 12 Spring CBH2390 13 Spring CBH2606 14 Spring CBH2607 15 Spring CBH2608 16 Spring CBH2609 17 Spring CBH2610 18 Spring CBH2735 19 Spring CBH2612 20 Spring CBH2613 21 Spring CBH2614 22 Spring CBH2615 23 Spring CBH2616 24 Spring CBH2617 25 Spring CBH2620 26 Spring CBH2621 27 Spring CBH2641 28 Spring CBH2642 29 Spring CBH2643 30 Spring CBH2659 31 Spring CBH2688 32 ••••• 33 Shaft CLA4441 34 Frame CNC9962 35 Frame CNC9963 36 Bracket CND2712 37 Bracket CND1895 38 Arm CNC9968 39 Arm CND1909 40 Lever CND2032 41 Lever CNC9984 42 Sheet CNM8134 43 Collar CNV7798 44 Guide CNV7799 45 Arm CNV8403 46 Rack CNV8374 47 Holder CNV8376 48 Holder CNV8377 49 Arm CNV8378 50 Gear CNV8379 51 Gear CNV8380 52 Gear CNV8381 53 Gear CNV8382 54 Gear CNV8383 55 Gear CNV8384 56 Rack CNV8385 57 Arm CNV8386 58 Arm CNV8387 59 Guide CNV8388 60 Roller CNV7218 61 Gear CNV8389 62 Arm CNV8391 63 Arm CNV8390 64 Arm CNV8392 65 Damper CNV7313 66 Damper CNV7314 67 Arm CNV8394 68 Arm CNV8395 69 Guide CNV8396 70 Guide CNV8397 71 Holder CNV8398 72 Arm CNV8402 73 Gear CNV8400 74 Damper CNV7618 75 Motor Unit(M1) CXC4440 76 Chassis Unit CXC2318 77 Screw Unit CXB8729 78 Gear Unit CXC2397 79 Arm Unit CXC2316 80 Arm CND1896 81 Arm CND1894 82 Motor Unit(M2) CXB8933 83 Bracket CNC9985 84 ••••• 85 Screw(M2x5) EBA1028 86 Screw JFZ20P020FTC 87 Screw JGZ17P022FTC 88 ••••• 89 Washer YE20FTC 90 Pickup Unit(P10)(Service) CXX1641 91 Screw IMS26P030FTC 92 Spring CBL1635 93 Clamper CNV8372 Mark No. Description Part No. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 20 1 2 3 4 1 2 3 4 C D F A B E 3. BLOCK DIAGRAM AND SCHEMATIC DIAGRAM 3.1 BLOCK DIAGRAM BA1-8 BA9-16 BA17-23 BA2-23,BD0-15 BA2-23,BD16-31 BA1-17,BD0-15 BA2-23,BD0-31 BD0-7 BD8-15 BD16-23 BD24-31 A2-16,D0-15 A2-16,D16-31 CPU IC2 UPD705103GM-180S1 97 4 XCS5 56 57 X2 X1 78 84 PORTB0/TI PORTB6/INTP02 PORTA5/DMARQ3 X1 30.000MHz SDRAM IC1 K4S561632E-TL75 (256MBit) BUS BUFFER IC103 TC74LCX245FTS1 FLASH ROM IC110 PEH007A FLASH ROM IC111 PEH008A SRAM IC113 M5M5V216ATP- 70HI SCARLET IC201 MB86291APFVS- G-DL BUS BUFFER IC104 TC74LCX245FTS1 SDRAM IC3 HY57V561620CLT-H (256MBit) 96 13 XCS6 95 5 XCS7 108 109 98 2 XCS4 100 CKE 13 105 1 XCS2 IC4 TC7SZ08FU IC102 TC7SH04FUS1 XCS5 XCS6 XCS4 XCS2 1 19 1 19 26 26 1 19 BUS BUFFER IC105 TC74LCX245FTS1 1 19 BUS BUFFER X202 14.31818MHz IC106 TC74LCX245FTS1 1 2 R/W IC101 TC74LCX08FTS1 2 4 4 37 37 11 A A B 124 128 6 XRST 44 S XINT XRDY XBS XCS 129 AOUTR 152 AOUTG 147 AOUTB 143 97 99 DCLKO 202 CSYNC 204 GV 207 39 XLLBEN SRAMC 40 XLUBEN 41 XMRD 17 XMWR 115 114 XRD 116 A24 179 XWE0 117 XWE1 118 XWE2 119 XWE3 120 DREQ 98 DRACK 107 DTACK 108 BCLKI OSCOUT CLK 113 28 XMRD 11 XMWR 28 12 12 XMRD XMWR 11 XIORD XIOWR REVSNS RQ BUP3 VCC3 VCC3 ANTVCC REVERSE RQ IOWR IORD 89 88 DREQ0 DREQ1 PORTA2/DMARQ1 87 DREQ2 PORTA4/DMARQ2 PORTA0/DMARQ0 82 77 INT2 INT3 PORTB3/INTP13 PORTB2/INTP00 106 85 XREADY INT0 PORTB7/INTP03 READY HYOKA IRQPWR PORTA7/DMAAK3 90 86 GDC_DMAACK GDC_DMARQ 94 XTC 107 XBCYST 115 XMRD 114 XMWR 113 XLLBEN 112 XLUBEN 111 XULBEN 110 XUUBEN CLKOUT 46 CPU_CLKGDC CPU_CLKASIC TC/STOPAK R/W CS2 CS4 CS5 CS6 CS7 63 RST3 RST3 RESET MWR MRD BCYST LLBEN LUBEN ULBEN UUBEN 83 99 GDC_INT PORTB4/INTP01 XCS3 CS3 LLDQM,LUDQM XWE,XCAS,XRAS,XCS0,SDCKOUT ULDQM,UUDQM A1-23 D0-31 D0-7 D8-15 D16-23 D24-31 A1-8 A9-16 A17-23 CC UNIT BUSP REVERSE, RQ BUSM ASENB0 BUSL BUSR AVV IPSEL1 IPSEL2 AVON MOTPW OPENSW CLOSESW CFSW PULSE1 PULSE0 MOT1 MOT0 BUS+ BUS− ASENB BUSL BUSR AVV IPSEL1 IPSEL2 AVON REMOUT FLPPW OPENSW CLOSESW CFSW PULSE1 PULSE0 MOT1 MOT0 BUS+ BUS− ASENB BUSL BUSR BUS+ BUS− ASENB BUSL BUSR VIDEO IPSEL1 IPSEL2 AVON COMP VIDEO IP-SEL1 IP-SEL2 AV ON REMOUT REMOUT FLPBUP FLPPW OPENSW HOMESW CFSW PULSE1 PULSE0 MOT1 MOT0 FLPBUP FLPPW OPENSW HOMESW CFSW PULSE1 PULSE0 MOT1 MOT0 30 29 27 26 20 24 22 15 19 18 17 7 14 13 8 3 6 5 4 2 1 1 2 4 5 11 7 9 16 12 13 14 24 17 18 23 28 25 26 27 29 30 1 2 4 3 11 10 7 8 9 16 12 13 14 25 17 18 15 19 20 22 42 28 40 41 51 54 69 70 72 1 5 8 7 9 CONNECTOR UNIT CN2804 IP-BUS INPUT CN2802 CN702 CN605 CN551 15 7 14 13 8 6 4 5 3 1 2 10 15 11 12 14 16 20 19 21 30 22 28 26 27 29 CN2806 2 12 4 5 10 AV-BUS INPUT CN2801 Q552 Q551 Q554 Q553 FLPBUP AD5V FLPBUP REVERSE RQ BUSP BUSM ASENB0 BUSL BUSR AVV IPSEL1 IPSEL2 AVON MOTPW OPENSW CLOSESW CFSW PULSE0 PULSE1 MOT0 MOT1 REVERSE SPEED SPEED RQ BUS+ BUS− ASENB0 BUSL BUSR AVV IRQPW IRQPWR RST3 VDD IPSEL1 IPSEL2 AVONIN MOTPW OPENSW CLOSESW CFSW PULSE0 PULSE1 MO0 MO1 CCD5 VDD5 SWAC56 CCD3 AD5V AD5V VSNS 4 1 CTOGPS GPSTOC GPSTOC0 CTOGPS0 GYROIN GSNSIN FLASHWE SPEED PSWOUT G SENSOR GY554 CSX1089 GYRO GY551 CSX1054 VOUT VCC AD5V BUP3S 3 OUT VIN AD5V CCD3 1 PULSE WAVEFORM CONV. 1 5 SPEED IC551 NJM2904M 2.5V REG. IC801 BA25BC0WFP 2 1 4 OUT CTL VCC CCD25C 4 16 6 9 SWITCHING REG. IC804 TPS5102IDBT SWITCHING REG. IC803 TPS5103IDB 8.0V 5V 3.3V PWM_SKIP 30 12 22 LH1 VREF5 COMP Q808 FU803 Q801 Q802 STBY1 LH2 RT 10 STBY2 17 18 19 LL2 OUT2_U OUT2_D 14 FB2 FU802 CCD5C CCV5 CCD5 BUPV CCD3 CCD3C SD3VC 15 INV2 Q807 29 28 27 LL1 OUT1_U OUT1_D 2 FB1 BUPV 1 INV1 5 13 VCC RT 10 STBY Q811 19 18 17 LL OUT_U OUT_D 3 FB DVD8 2 INV 3.3V REG. IC802 S-818A33AUC-BGN 5 1 VOUT VIN BUP3C VDD5 BUP3S BUS BUFFER IC109 TC74LCX541FTS1 BUS BUFFER BUS BUFFER IC107 TC74LCX541FTS1 IC108 TC74LCX541FTS1 14 VCC-SENSE B 3V REG. A K L CN2 G CN1701 B CN461 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 21 5 6 7 8 5 6 7 8 C D F A B E SH ROM C110 EH007A SH ROM C111 EH008A SRAM C113 5V216ATP- 70HI CARLET IC201 291APFVS- G-DL 28 32 33 34 35 36 37 38 27 | 12 11 10 9 8 7 6 5 4 3 2 1 ATA_XRESET 114 ATA_DMARQ ATA_XDIOW ATA_XDIOR ATA_IORDY ATA_XDMACK ATA_INT ATA_DA1 ATA_DA0 ATA_DA2 ATA_XCS0 ATA_XCS1 182 109 246 181 180 179 178 177 191 257 192 DMARQ IORDY INTRQ DA1 DA0 DA2 CS3FX CS1FX DMACK DIOR DIOW EJSW HRESET IC112 TC7SH00FUS1 IC114 TC7SH08FUS1 IC309 TC7SH08FUS1 Q201 RST3 1 XCS_SRAM 2 6 2 SRAM_CSE 1 2 4 1 2 XRSTMS3 4 4 CCD3C CCD3C XRST 44 S XINT XRDY XBS XCS 129 AOUTR 152 AOUTG 147 AOUTB 143 11 XCS_SRAM 44 PIO4 97 99 GDC_INT AOUTBLUE DCLKO 202 FSC CSYNC 204 OUTCSYNC GV 207 OVER AOUTGREEN AOUTRED 39 XLLBEN SRAMCS 40 XLUBEN 41 XMRD 17 XMWR GDC_WT XBCYST XCS4 XMRD XMWR XLLBEN XLUBEN XULBEN XUUBEN GDC_DMARQ GDC_DMAACK XTC 115 114 XRD 116 A24 179 XWE0 117 XWE1 118 XWE2 119 XWE3 120 DREQ 98 DRACK 107 DTACK 108 ASIC IC5 PD6336C 33 CPU_CLKASIC CPU_CLK 169 XBCYST XBCYST 238 XCS5 XCS5 171 XCS3 XCS3 170 XCS2 XCS2 GDC_WT 101 GDC_WT XMRD 88 XMRD XMWR 163 XMWR XLLBEN 164 XLLBEN 231 XLUBEN 97 XCS6 XCS6 90 XIOWR XIOWR 165 XIORD XIORD XLUBEN GPSTOC0 30 UART2_RX 29 CTOGPS0 UART2_TX 55 56 134 CN2 RST3 CPU_CLKGDC BCLKI T 113 6 DACOUTL 11 3 DAC_BCLK DAC_LRCK DAC_DATA 76 DSP_XHINT DSP_XHINT 75 DSP_HRDY DSP_HRDY DAC_BCLK 135 DAC_MCLK DAC_MCLK DAC_LRCK DAC_DATA 126 48 85 KMODE ILM PBSNS PIO28 PIO12 PIO11 110 49 127 CPUWDT XCCSTBY SYSTOC PIO13 PIO14 UART3_RX 129 27 CTOSYS ONSEIMUTE UART3_TX PIO17 28 XMRD 11 XMWR 28 12 12 XMRD XMWR 11 176 175 94 172 173 240 174 XREADY INT0 INT2 INT3 DREQ0 DREQ1 DREQ2 XREADY PIO29 INT0 INT2 INT3 DREQ0 DREQ1 DREQ2 DAC IC304 AK4351VT IC602 TC7SH14FUS1 MCLK AOUTL RST3 RST3 5 BICK 4 SDATA DAC_MCLK DAC_BCLK DAC_DATA DAC_LRCK 2 LRCK ATA_DMARQ ATA_DD0-15 ATA_XRESET PIO18 PIO3 ATA_XDIOW ATA_XDIOR ATA_IORDY ATA_XDMACK ATA_INT ATA_DA1 ATA_DA0 ATA_DA2 ATA_XCS0 ATA_XCS1 51 DISC XRESET DVDEJECT 42 ATA_DD0-15 2 5 6 CCD3C RESET GEN. IC301 M51957BFP Q301 Q601 TH601 Cd IN1 RSTOUT IC302 TC7SH08FUS1 1 2 4 PD B 60 58 XTAL1 EXTAL1 X3 33.8688MHz 18 16 XTAL0 EXTAL0 X2 33.000MHz B CCD5 DVD8 VDD5 VDD8 RST3 34 31 37 43 47 46 49 50 52 53 55 57 56 58 60 59 62 64 63 66 67 76 77 FMONV NAVIV GUIDE KMODE ISEN PKBSNS DRAMPW CCON SYSRST CPUWDT XCCSTBY STOC CTOS FCONT DRAMPW CCON1 FCONT ONSEIMUTE KMODE ILM PBSNS CPUWDT XCCSTBY SYSTOC CTOSYS ONSEIMUTE NTEMPIN STOM MTOS SWACPW MEMOLED HDRST KEYILM MONVBS STOM MTOS SWACPW MEMLED HDRST ILMB Q604 Q603 Q753 Q752 Q751 Q754 IR_RX 14 NTSC ENCORDING IC752 BH7236AF IC751 TC7SH08FUS1 IC753 TC7SH08FUS1 BIN GIN RIN SYNCIN GOUT ROUT 21 22 23 4 3 2 CCON1 CCON1 BUPD1 UART5_RX UART5_TX UART7_RX UART7_TX RS232C DRIVER IC651 UPD4721GSS1 DIN1 ROUT1 DIN2 ROUT2 DOUT1 RIN1 DOUT2 RIN2 14 12 13 11 21 104 25 24 7 9 8 10 CTOEX EXTOC HYOKA CTOTA TATOC CTOEX0 FU651 Q652 Q651 EXTOC0 CTOB0 BTOC0 PIO9 125 ANTON0 VTA 4 5 6 7 9 8 TO XM TUNER A 4 16 6 9 CCON1 CCON1 DRAMPW FCONT CHING REG. IC804 5102IDBT CHING REG. IC803 S5103IDB PWM_SKIP 30 12 22 LH1 VREF5 COMP Q805 Q803 STBY1 LH2 RT 10 STBY2 U D U D 5 13 FCONT CCON1 Q804 VCC RT 10 STBY U D BUPD1 CN801 1 3 5 6 11 18 20 9 10 PWRVI FLPBUP BUPD1 BUPV VDD5 PWRVI MFLPW0 SWACPW PWRFL + Q813 Q814 Q809 Q806 PWRFL 2 1 7 8 15 17 21 19 18 13 23 22 25 28 26 29 31 33 32 YS CN701 PWRFL PWRVI CSYNC OVER OUTSYNC 4 4 1,2 1,2 ANB ANG ANR MONVBS ILMB HDRST MOREM REM_IN0 REMOUT 4 2 MTOS STOM MFLPW MFLPW0 SWACPW MEMLED MONVBS ILMB HDRST MTOS STOM SWACPW MEMLED SCIN VOUT 20 6 AOUTBLUE AOUTGREEN AOUTRED FSC SWAC56 14 VCC-SENSE 108 XRESET PWRFL PWRVI 10 BOUT CN651 G CN1701 G CN1802 H CN5002 C CN601 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 22 1 2 3 4 1 2 3 4 C D F A B E SYSTEM UNIT CN4300 CN1301 CN1651 CN1450 FM/AM TUNER UNIT WIRED REMOTE VDD_3.3 1 3 VCC ROM_VDD DI DO CE1 CK SL CE2 TUNPDO TUNPDI CCON TUNCE1 TUNCK TUNSL TUNCE2 TUNPDO TUNPDI TUNCE1 TUNCK TUNSL TUNCE2 Lch Rch TUNL TUNR AM_ANT FM_ANT 1 3 23 24 5 6 8 9 10 14 4 13 17 5 4 2 1 2 3 4 8 10 12 14 15 17 18 19 5 6 7 VDORA85 VDORA85 VDD5 VD56 VD83 VDD5 WCONT VDCONT BSCK BDATA RESET CSENS ROUT LOUT BSRQ BRXEN BRST CDR CDL VD VD2 CN1802 CN1701 20 18 16 15 10 3 1 12 11 PWRVI FLPBUP BUPD BACKUP2 PWRFL CD3VON WREMIN 3.3V REG. IC4301 NJM2391DL1-33 TUNL TUNR 40 38 11 23 RL1 RR1 41 37 13 12 1 8 VCRINL VCRINR 43 35 CDL CDR 42 36 BUSL BUSR Rearout_L IN2L Rearout_R 12 22 10 24 SWL1 SWR1 Preout_L Preout_R IN2_R IN4+_L IN4+_R VCK VDT 17 18 CLK DATA VST 19 STB MUTEVOL VCK VDT VST MUTEVOL NOSELL ONSEIMUTE1 ONSEIMUTE1 MUTENS 20 MUTE IN1L IN3L IN1_R OUT1 OUT2 IN1A IN2A Frontout_L Frontout_R IN3_R IC4401 TA2050FS1 1 2 5 6 8 DIN1 DOUT STBN BUS− BUS+ IP-BUS DRIVER IC1601 HA12240FP IC1506 S-80840CNMC-B8Z RESET Q4501 Q4502 Q4500 (2/2) Q1201 Q1502 Q4211 (2/2) Q42 (1/2 Q4500 (1/2) Q4503 (2/2) Q4503 (1/2) D4500-D4503 1 7 3 DACOUTL1 5 A_OUTPUT B_OUTPUT A+INPUT B+INPUT LPF IC4500 NJM2068V L/R SW(MUTE) AUDIO SELECT IC4001 PML009A 22 23 VCK TUNCE1 VDT 24 25 95 99 77 96 98 97 14 3 13 30 34 15 16 17 80 79 52 51 53 AMPSTB 65 MUTEALL 67 MUTEAMP 68 VST MUTEVOL TUNCK MUTEAMP MUTEALL AMPSTBY X1 X2 56 1,2 4 2 4 1 2 4 IRQPW RESET BSI BSCK BSO WREMIN 93 DVDEJECT 94 CDEJECT 6 MTOS 63 MEMOLED 62 FLAPILM 7 STOM 2 FCONT 1 STOC 57 SYSRST 54 DRAMPW 47 MOTPW 46 MOT1 45 MOT0 27 TX 26 RX 28 IPPW 78 TEMP 100 CTOS 82 XCCSTBY 81 RST3 83 CPUWDT 19 VSELIN2 18 VSELIN1 20 50 EJECTSW 49 48 44 PULSE1 43 PULSE0 WCONT TUNSL TUNPDO TUNPDI SYSTEM MICRO IC1502 PE5478A REARON 73 VRSEL 72 VFSEL1 70 VFSEL1 VRSEL REARON 12 SYSPW 61 ILMPW SWACPW 11 FANUP 66 FANUP CCON 55 CCON SWACPW VFSEL0 69 VFSEL0 29 ASENB0 84 92 91 ASENS ILMSEN TELIN 60 ANTPW 85 PBSENS NOSELR ASENS 90 BSENS BSENS PKBSNS HDRST 86 REVSENS REVSNS ANTPW ISENS TELIN Q1501 (2/2) Q1501 (1/2) S1501 Q4202 (2/2) Q4202 (1/2) AV85 AV85 Q1503 (1/2) Q1503 (2/2) VDD5 MBUP MUTEAMP MUTEALL RESETM RQ RESET IRQPW3 AMPSTB VCRINV AVV VFSEL0 VFSEL1 VRSEL BACKV VDCONT REARO FMONV NAVIV BUS− BUS+ BUS− BUS+ MEMOLED MTOS STOM NTEMPIN FCONT STOC MEMOLED MTOS STOM NTEMPI FCONT STOC CTOS XCCSTBY RST3 CPUWDT CTOS5 XCCSTBY5 RST3U CPUWDT 12,13 4,5 9,10 1,2 11 6 8 3 SYSRST DRAMPW IPSEL2 IPSEL1 CFSW MOTPW CLOSESW OPENSW PULSE1 PULSE0 MO1 MO0 ONSEIMUTE IRQPW ASENB0 GUIDE BUSR BUSL HDRST AVV RQ HDRST RQ ONSEIMUTE1 DACOUTL1 BUSR BUSL CFSW MOTPW PULSE1 PULSE0 MOT1 MOT0 AVONIN SYSRST DRAMPW VSELIN2 VSELIN1 VDD2 Q1941 Q1940 Q1924 Q1920 VD83 VD56 BUP DVEJKY CDEJKY PNLILM Q1601 Q1602 Q1942 Q1943 (1/2) Q1943 (2/2) BUP BUPV CN5901 DVEJKY CDEJKY PNLILM 5 4 2 S5902 S5901 D5901-D5906 NAVIV KEYILM FMONV 15 18 66 67 19 21 23 25 24 26 27 28 29 32 22 30 65 78 14 63 64 68 69 70 71 72 73 74 44 56 59 53 50 61 62 47 4 5 7 1 7 3 2 1 1 1 1 3 2 5 2 3 2 3 2 3 4 FRONT VIDEO SELECTOR IC1201 NJM2235V VIDEO ISOLATOR IC1002 NJM2137V IC1001 NJM2137V IC1003 NJM2137V REAR VIDEO SELE IC1202 NJM2235V VD VDORA85 ILMPW − + − + − + NOSELL NOSELR AVONIN CLOSESW OPENSW MEMOLED MTOS STOM NTEMPI FCONT STOC CTOS5 XCCSTBY5 RST3U CPUWDT CFSW MOTPW PULSE1 PULSE0 MOT1 MOT0 BUS− BUS+ SYSRST DRAMPW VSELIN2 VSELIN1 AVONIN AVONIN CLOSESW HOMESW OPENSW OPENSW MUTENS 4 EQSW BRST BRXEN RESET RESET BSRQ CSENSOUT TUNCE2 CN605 3V→5V IC1501 TC74VHCT08AFTS1 5V→3V IC1503 TC7SH08FUS1 FLAPILM IC1505 TC7S04FU IC1507 TC7SH00FUS1 B B C A A 1 SYSPWR AD IN IC190 M5237 BUP Q1922 FU1900 FU1920 Q1904 Q1903 Q1902 Q1923 (1/2) Q1923 (2/2) BUP X1501 12.58MHz 39 38 VDD 1 2 VD2 A CN801 A CN901 F G PANEL PCB J www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 23 5 6 7 8 5 6 7 8 C D F A B E CORD ASSY(AV) CORD ASSY(POWER SUPPLY) CN1401 FRONT REAR SUB WOOFER and NON FADER OUTPUT AUDIO INPUT VIDEO INPUT BACK CAMERA INPUT REAR MONITOR OUTPUT ASENS BSENS RL1 RR1 VCRINL VCRINR SWL1 SWR1 RL1 RR1 SWL1 SWR1 FR1 MUTERCA FL1 RL RR SWL GNDVCRL SWR SWL FR FR FL GNDA VCRV GNDA GNDA RL GNDVV VCRR FL GNDA BACKV GNDVCRR GNDA SWR BACKVG REARV VCRINV BACKV REARV GNDVR FU1401 VCRL VCRINR VCRINL RR SWL FR RL FL SWR RR GNDA GNDVCRL SWL FR GNDA VCRV GNDA GNDA RL GNDVV VCRR FL GNDA BACKV GNDVCRR GNDA SWR BACKVG REARV GNDVR VCRL RR GNDA Vout Vsag Vin POWER_SAVE 9 6 FL1 FR1 14 1 D_OUTPUT A_OUTPUT C_INPUT Q4205 Q4208 Q4501 Q4502 500 2/2) Q1201 Q4211 (2/2) Q4211 (1/2) Q4210 (1/2) Q4209 Q4210 (2/2) Q4500 (1/2) 503 2/2) Q4503 (1/2) D4200,D4201 D4204 Q4207 Q4206 Q4203 Q4204 B_INPUT AUDIO MIX AMP IC4100 NJM2058V 1 6 ANTENNA ON IC1801 TPD1018F L/R SW(MUTE) 9 21 7 23 5 17 3 FR1 RR1 FL1 RL1 11 15 12 14 19 POWER AMP IC4200 PAL007B RL+ FR+ RL− FR− RR+ FL+ RR− FL− FRIN RRIN 22 MUTE 4 STBY FLIN RLIN 25 B.REMOTE PKBSNS ANTPW ISENS 1 2 10 11 12 16 17 18 19 20 21 22 23 24 13 14 5 6 7 8 9 15 CN1801 1 2 10 11 12 16 17 18 19 20 21 22 23 24 13 14 5 6 7 8 9 15 Q4212 Q1802 Q1820 TELIN BACKV, VCRINV Q1821 Q1861 Q1810 Q4202 (2/2) Q4202 (1/2) Q4201 MUTEAMP MUTEALL MP L RESETM RESETM RSMT OFMT B OFMT VRSEL REARON ONV VIV MBUP FL− FL+ FR− RL+ FR+ SPEED PULSE SPEED RR+ FANCNT RL− RR− SYSTEM REMOTE BREM PARKING BRAKE KMODE VGND B.UP GND KMODE VGND B.UP GND A.ANT FL− FL+ FR− RL+ FR+ RR+ RL− RR− KMODE ISENS FANCNT FANUP SWACPW CCON CCON Q1960 MUTE ILL REVERSE SIGNAL 1 2 3 4 8 9 10 11 12 18 19 20 17 5 6 7 16 15 14 13 1 2 3 4 8 9 10 11 12 18 19 20 17 5 6 7 16 15 14 13 ACC SPEED PULSE SYSTEM REMOTE PARKING BRAKE A.ANT MUTE ILL REVERSE SIGNAL ACC SPEED SPEED REVERSE VDD ISEN PKBSNS SWACPW CCON SWACPW CCON KMODE PKBSNS KMODE 10A 1KΩ 1KΩ GND BACK UP CELLULAR MUTE ILL REVERSE-GEAR SIGNAL INPUT ACC AUTO-ANTENNA REMOTE CONTROL PARKING BRAKE CAR SPEED SIGNAL INPUT FL− RL− FL+ RL+ FR− RR− FR+ RR+ SYSTEM REMOTE CONTROL 39 40 12 9 11 34 41 38 35 79 77 80 17 31 FAN MOTOR Q1833 (1/2) Q1833 (2/2) Q1882 Q1881 BUP Q1884 FU1880 Q1885 CN1803 2 Q1860 (2/2) Q1860 (1/2) BUP MBUP + + + BUP BUPD FLPBUP PWRFL BACKUP2 FU1820 FU1821 PWRVI FU1830 FU1823 + + + REARV REVSNS 7 4 1 2 3 1 7 3 2 LECTOR V REAR VIDEO SELECTOR IC1202 NJM2235V IC1204 NJM2561F1 VD ORA85 D D C + 3 1 ADJ IN IC1900 M5237ML VDORA85 VD83 Q1922 Q1902 Q1923 (1/2) Q1901 (1/2) Q1901 (2/2) Q1900 BACKUP2 AV85 AD5V 3 2 AD5V REG. AV85 IC1902 S-812C50AUA-C3E Q1850 (1/2) Q1850 (2/2) Q1842 Q1841 Q1851 VDD5 VDD2 SWAC56 3 2 VDD5V REG. SWAC56 IC1840 S-812C50AUA-C3E FU1840 AD5V CCD5 CCD3 VDD5 SWAC56 A SENS REVERSE SENS ILM SENS TEL MUTE K MODE PARKING SENS B SENS www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 24 1 2 3 4 1 2 3 4 C D F A B E 1 3 4 2 2 1 7 31 33 8 15 17 21 19 18 13 23 22 32 25 28 26 29 PNLADY PNLADY PNLVD PNLADX PNLXV PNLYV MFLPW 10 4 1,2 PWRFL YS YS CN5007 VIDEO PROCESS BLO IC5001 TC90A64AF-P CN5002 CN5009 IC5061 TC7SH08FUS1 BUP (VFL) PWRVI BUP (V14) 4 1,2 NVSYNC NVSYNC NVBLUE IC5026 TC7SH00FUS1 TEMP.Sens ANB NVGREN ANG NVRED CSYNCO ANR CSYNCO ILMB ILMB SWACPW HDRST HDRST MEMLED MEMLED Q5101-Q5103 FILTER ACC5V Q5603 Q5683 (1/2) Q5683 (2/2) Q5682 (1/2) Q5682 (2/2) Q5681 (1/2) Q5681 (2/2) VSW5V VSW5V MFLPW X1 X2 TEMPSEN PIPRES 62 VDDSENS SYSTOM 8 RXD REMIN REMIN 61 REMIN MTOSYS KDT0 KDT3 LSEN KDT1 KDT2 9 78 76 77 2 79 TXD KEY2 KEY0 KEY1 KEY3 LSEN 18 17 5 14 OSDCK OSDDT 21 EPRTEST OSDCS DIMMER 44 INVPUL 13 MVIPW 6 INVBST_DA OSDCK OSDDT OSDCS EPRTES OSDCK OSDDT OSDCS EPRTES 20 13 18 19 17 14 8 11 12 10 9 2 3 70 X5601 69 XO XI 82 X5001 83 OSDCK OSDDT OSDCS OSDG OSDB OSDR OSDV SCKE OSDH BLK OSDG OSDB OSDR OSDV SCKE OSDH BLK OSDG OSDB OSDR OSDV SCKE OSDH BLK EPRTES VCC V332 9 100 CLAMP0 NDSV SCKE 101 91 90 OSDB OSDG 89 OSDR BLNK 92 ANR ANG CSYNCO NVSYNC YS ANB 93 104 29 18 FNAVI RESET HDIN 53 52 GIN RIN 65 CVI1 BIN 54 SCL 96 28 IICCK SDA 99 27 RESET 60 1 EPRCS 46 3 EPRSK 47 4 EPRDO 48 5 EPRDI 49 6 EPRPROT 50 8 2 IICDA BOUT STH1 CX CPH POLC CPV STV1 CDAO CKIN GOUT ROUT DIMOFF BUP (VFL) Q5351 7 80 6 2,5 5 14 15 LCT 3 ENA 7 V2500 18 CT 9 FB DIM VDDA Q5343 Q5342 Q5331 Q5332 Q5373 Q5371 DIMMER BLOCK IC5901 NJM2903V IC OZ INVERTER TH5601 1 31 3 PNLADX PNLVD PNLADY PNLADX PNLVD PNLADY 24 25 PNLXV PNLYV PNLXV PNLYV IC5651 S-29221BROI-J8T1 EEP-ROM IC5602 S-80835CNNB-B8U POWER ON RESET MONITOR PCB TOUCH PANEL 4 1,2 IC5333 TC7SH08FUS1 MONITOR CPU IC5601 PE5479A PNLADX PNLYV PNLXV VSW5V PNLYV VSW5V (BUP)V14 3 4 3 4 D/D CONVERTER IC5851 BD6171KV 3.3V 11 6 PVCC1 PVCC2 32 EN1 OUT2 7 VS2 4 PVCC3 PVCC4 PVCC5 23 48 37 OUT1 10 OUT5 38 OUT4 47 OUT3 22 Q5 8V Q5 41 DVCC 42 VCC VS1 13 2.5V REG. V25 V332 IC5841 R1130H251B 2 5 1 CS SK DI DO PRO CN701 A H www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 25 5 6 7 8 5 6 7 8 C D F A B E EO PROCESS BLOCK IC5001 TC90A64AF-P RGB AMP CN5801 CN5331 VCOM AMP IC5181 NJM082BV XO XI CLAMP0 NDSV SCKE OSDB OSDG OSDR BLNK FNAVI RESET HDIN GIN RIN CVI1 BIN IICCK IICDA BOUT 38 STH1 14 STH1 CX 13 CX CPH 8 POLC 28 6 7 2 3,8 1 5 CPH VCOM L/R VDD3 VR VG VB CPV 4 CPV STV1 2 CDAO Q5002 72 CKIN 74 STV1 GOUT 36 ROUT 34 5 20 14 15 5 4 3 6 7 2 LCT 3 ENA 7 V2500 18 CT 9 FB DIM VDDA NDRV_B 19 PDRV_A 11 NDRV_D 12 PDRV_C 2 OVP 17 RT Q5342 Q5333 Q5334 Q5373 Q5371 Q5372 Q5380 VR5331 Q5375 (1/2) Q5375 (2/2) IC5331 OZ961ISN RTER T5331 IC5151 NJM2138V Q5151-Q5153 Q5154 | Q5156 28 20 26 27 24 22 12 17 23 2 7 5 15 13 CN5008 CN5700 IC5700 SBX3050-01 IC5701 TC7SH08FUS1 REMOTE CONTROL SENSOR OPTICAL SENSOR 3 8 5 4 6 7 12 10 11 2 3 8 5 4 6 7 12 10 11 +- +- V332 VGH V18 VDD5 V5 VGL FLP FLW KDT3 REMIN 2 IC5702 TPS850 4 4 1,2 1 3 KDT2 KDT1 KDT0 S5700 RESET Q5703 Q5701 Q5702 D5712 D5700-D5711 D5713-D5716 MEMLED HDRST REMPWR(5V) DESTINATION S5715 WIDE S5709 S5716 ANGLE S5710 MEMO SOURCE S5701 S5702 VOL− S5703 VOL+ S5704 AV MAP S5718 S5719 TRAFIC S5717 OPEN INFO S5720 VM12 1 2 2 LSEN LCD PANEL KDT0 KDT1 KDT3 LSEN KDT2 HDRST MEMLED ILMB KDT0 KDT1 KDT3 LSEN KDT2 HDRST MEMLED ILMB ILMB(10V) REMIN REMIN VSW5V REMPWR REMPWR REMPWR KEYBOARD PCB S5713 1,2,5,6 1,2,5,6 3 4 3 4 NVERTER 5851 71KV 3.3V REG. OUT2 7 VS2 4 PVCC3 PVCC4 PVCC5 23 48 37 OUT1 10 OUT5 38 OUT4 47 V8 V33 V332 V18 OUT3 22 V5 VM12 Q5831 8V REG. Q5832 VS1 13 V8 Q5182 (2/2) Q5182 (1/2) Q5183 (1/2) Q5183 (2/2) VM12 I www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 26 1 2 3 4 1 2 3 4 C D F A B E 26 23 24 19 18 9 22 20 17 12 16 14 13 11 10 7 5 4 3 15 2 1 20 18 15 17 16 14 9 13 11 10 8 7 6 5 4 3 12 2 1 78LD 65MD C B4 RF+ B3 RF− B2 B1 A SW TEMP O TE CD/ VREF MDC VSHF 65LD Q1101 Q1102 Q1105 Q1104 Q1103 VCC 78MD F+ F− FOP FOM T− T+ TOP TOM CN1101 CN1201 CN1202 IC1202 BA6859A VCC5 VCC5 V H1+ H1− H3− H2− VH A3 A2 H2+ H3+ A1 CRGR1 CRGR2 CRGD1 CRGD2 COIL_V COIL_V 8cm Photo 8cm disc ditect 12cm COIL_W COIL_W COIL_U HALL_BIAS− HALL_W− HALL_W+ HALL_V− HALL_V+ HALL_U− HALL_U+ HALL_BIAS+ SWITCH COIL_U 5 4 6 14 13 12 11 10 9 8 2 1 5 4 3 PICKUP UNIT(SERVICE) CARRIAGE MOTOR SPINDLE MOTOR LOADING MOTOR S1206 S1202 S1203 S1204 S1201 S1205 CLAMP SW 12cm 8cm 8cm Disc sens Disc sens COMPOUND UNIT(B) COMPOUND UNIT(A) 5 6 2 3 4 DVD CORE U C D E SL SD 28 3 1 PLIO2 CN461 CN504 22 21 CTOGPS SPEED REVSNS RQ 8 9 133 132 16 20 1 4 1 6 7 1 4 17 19 22 110 130 131 120 140 143 5 2 X401 IC 502 PD6519A FLASH ROM IC 503 M5M5V216ATP-70HI DRAM CRCK PIN0 PIN1 BOWWOWB RESETB IF Q441 IC 461 ADC12H034CIMSAS1 RXD0 GPSTOC 7 19 TXD0 SPEED PSWOUT 17 15 ADIO2 PIN2 PIN3 IC 401 UPC2749T F401 CTF1548 IC 402 UPB1027GS IC 441 NJM2100V IC 501 PD3390A DRAGON RESET IC 504 MAX6364PUT29 BUP3V 128 129 X502 20.00MHz 16.368MHz XAUXIN XAUXOUT 102 103 X501 32.768kHz XRTCIN XRTCOUT 3 2 12 11 GSNSIN GYROIN GPS ANTENNA CPU 13 3 PLIO2 GPS UNIT B CN551 A www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 27 5 6 7 8 5 6 7 8 C D F A B E DA0-2 HDD0-15 A0-17 D0-7 45 41 44 43 | 40 39 37 38 36 35 34 19 | 18 8 10 9 11 CN601 HCS1 OEIC TEMP CD/DVD Q1101 Q1102 Q1105 4 Q1103 FOP FOM TOP TOM LPCO1 LPCO2 VREF1 VIN10 VIN9 VIN12 VIN1 RFINN VIN2 VIN3 2 6 4 56 54 53 59 63 57 48 RFINP VIN4 60 47 VIN11 LPC1 1 LPC2 3 62 58 VIN5 VIN6 VIN7 51 49 50 IC1101 AN8703FH FEP IC1301 MNZS26EDCUB SODC IC1202 BA6859AFP-Y LTFEP TOP TOM FOP FOM FD TD MD CRGDRV CC5 VCC5 VCC5 7 16 18 20 21 22 30 31 39 40 41 46 65 66 136 135 HINTRQ 141 142 IORDY 145 146 HDMARQ 147 148 14 DISC 13 EJ 12 XRESET 175 84 118 119 117 110 111 51 52 120 82 VIN8 TBAL FBAL FEN TEOUT FEOUT DFLTOP OFTR RFENV TESTSG 12 SEN SCKCOMN 13 SCK SOCOMN 14 STDI H1+ H1− H3− H2− VH A3 A2 H2+ H3+ A1 IC1201 BA5985FM VO4(−) VO3(−) OUTPUT2 VO3(+) VO4(+) OPIN1(−) OPIN3(−) OPIN4(−) OPIN2(+) FG EC PS JLINE ASOUT DFLTON BDO TBAL FBAL AD0 AD1 ARF OFTR AD3 TESTSG JLINE AD2 NARF BDO NCS3FX NCS1FX INTRQ NIORD NIOWR IORDY DMARQ NDMACK NRESET DAC1 DAC0 SPDRV TRSDRV FG 52 5 4 6 14 13 12 15 16 17 18 LTFEP SCKCOMN SOCOMN 95 96 91 79 CD/DVD TEMP OEIC 93 74 99 3 5 23 26 11 10 9 8 22 FG 20 7 1 8 28 9 21 10 21 VO1(−) VOL+,- 13 9 10 VO1(+) SO0 P05 P15 P75 SCK0 ANI0 P07 TO2 TO3 P30 75 ANI1 76 ANI2 FWD 46 P96 78 DVD8 31 4 1 2 1 2 36 35 P74 X1 X2 REV MUTE 14 FD TD FG MD 68 69 114 115 CRGDRV 67 XWR XRD XODCRES DVDLOCK P83 P25 85 5 43 40 CDLOCK P82 84 WAITODC INTP1 INTP0 INTP3 39 90 88 87 XWR XRD XODCRES DVDLOCK MONI0 NRD NWR NRST 127 47 36 35 CDLOCK MONI1 128 WAITODC WAITODC NINT1 NINT0 NINT2 6 5 2 1 IC401 PE5430A CPU IC402 S-80827CNNB -B8M 1 3 1 3 IC601 BA033FP 3.3V REG IC602 BA18BC0FP 1.8V REG IC404 TC7S08F X401 16.00MHz 80 79 OSCO1 OSCI1 X1301 VCC33 VCC5 VCC33 VCC18 VD8 HCS0 HDMACK DIOR DIOW HRESET INT0 INT1 INT2 INT0 INT1 INT2 WAIT WRL RD RESET D CORE UNIT CN2 A www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 28 1 2 3 4 1 2 3 4 C D F A B E CN2 MOT0 MOT1 PULSE0 PULSE1 HOMESW OPENSW S1 OPEN SW S2 HOME SW 7 5 IC2 S-812C50AMC-C3E IC1 BA6288FS 6 11 3 14 1 2 IC3 TC7W14FU 2 3 4 5 8 IC4 GP2L24B 2 3 IC5 GP2L24B 2 3 1 3 Q1 2SB1185 M FLAP MOTOR CN1 15 14 13 12 10 9 1 3 2 FMRF ANT adj RF adj FM ANT T51 CF52 CF51 RFGND OSCGND DGND AUDIOGND NC VCC VDD_3.3 3.3V 2.5V IC 4 3.3V 2.5V ← IC 2 2.5V WC CE2 ROM_VDD SL DI CK CE1 NC DO NC NC NC NC 7 6 13 5 10 9 8 11 14 18 19 20 21 1 3 2 12 15 22 16 4 17 IC 1 3.3V AM ANT FMRF ATT LPF OSC IC 3 EEPROM 5.0V IC 5 5V 3.3V ← ATT MIXER, IF AMP DET, FM MPX G G G MAIN PCB UNIT L FM/AM TUNER UNIT K CN2806 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 29 5 6 7 8 5 6 7 8 C D F A B E IC 2 2.5V DET, FM MPX 24 23 Rch Lch G BRST,BRXEN,BSRQ CN901 Q101 M LASER DIODE MONITOR DIODE S903 DSCSNS FOCUS ACT. M1 SPINDLE MOTOR M M2 LOADING/CARRIAGE MOTOR TRACKING ACT. LD- MD FOP TOP 15 5 1 4 PICKUP UNIT (P10)(SERVICE) HOLOGRAM UNIT IC 301 BA5835FP IC 201 UPD63763GJ IC 703 3V REGULATOR RF AMP, CD DECODER, MP3 AND WMA DECODER, DIGITAL SERVO/DATA PROCESSOR CD DRIVER 3 VD VD 3VDD 10 LOUT 5 CN101 TOP FOP 16 SOP 15 SOM 18 LCOP 17 LCOM 22 2 LOEJ 31 LOUT 9 CONT 12 FOP FD,TD AC,BD E,F SD,MD 3 13 TOP S901 HOME S904 12EJ S905 8EJ LD+ 14 142 LD 143 PD 13 12 X701 DSCSNS CONT LOEJ HOME 32 97 53 47 VDD IC 203 NJM2885DL1-33 3.3V REGULATOR V3R3D 1 3 VDCONT 49 S-812C33AUA-C2N MICRO COMPUTER IC 701 PE5454B 4 V3R3D 19 BDATA,BSCK VD2 VDD 2 15 5 1 4 14 VD2 VDCONT 30 31 8EJ 12EJ X1 X2 CD CORE UNIT(S10.1) F G CN1301 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 30 1 2 3 4 1 2 3 4 C D F A B E B.U (CC) 14.4V BUP 13.8V 0.70W typ typ 47mA (Max 110mA) VDD5 0.27mA 5.0V Reg 3.3V Reg SRAM3 Max 110mA [IPPWR] 7.7mA 24mA Max 40mA (typ 25mA) BUPV [DRAMPW and CCON] Max 1880mA CCD3 [CCD5] Max 580mA SD3V (Max 420mA) 400mA 280mA 3.3V D/D 5V D/D 8.0V D/D [CCON] Max 550mA [CCON] Max 493mA CCD5 DVD8 200mA (Max 1600mA) CCV5 CCD5 20mA CCD2.5 220mA CCD3 24mA CCD2.5 660mA CCD3 2mA 2.5V Reg [CCON] CCD2.5 Max 0.62W Max 880mA SYS µ-com SDRAM SRAM ASIC, ROM GDC : outside V833 : outside inside inside DAC Reference LPF, SW AU4.7 11mA Max 201mA 5.0V Reg AD5 22mA [CCON] 8.5V Reg Max 1.38W AV85 234mA 0.1mA (Max 60mA) 0.1mA (Max 60mA) Max 180mA 3.3 ± 0.1V typ 4.5m 300 200 VCC5 ± 0.25V (Max 400mA) DVD8 ± 0.4V (Max 1600mA) 57mA 15mA 11mA 30mA 43mA 28mA 15mA 17mA typ 103mA (Max 14 VDORA33 typ 172mA (Max 20 typ 20mA (Max 60mA) typ 200mA (Max 1000mA) typ 200m 3.3V Reg 275mA (Max 340mA) [SYSPWR] [CCON] 8.5V Reg 8-12V Reg Fan Motor POWER AMP 1.85W [FANUP] [VDCONT] VDORA85 5.6V Reg VD VD2 5.6V Reg SWAC56 Max 95mA [SWACPW] [CD3VON] PWRFL PWRVI [ILMPW] [FLAPILM] [MOTPW] DRIVER Flap Motor - Power supply system figure FU1840 0.25A FU802 2.5A FU803 1A FU1823 4A FU1900 1A FU1880 0.5A 8.3V D/D FU1920 1.75A FU1821 2A FU1830 1A FU1820 2A www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 31 5 6 7 8 5 6 7 8 C D F A B E PWR] 7.7mA 24mA IP-BUS 232C Driver GPS Unit SRAM DRAGON A/D Con. DVD Core Unit VDD5 DVD8 E. Volume IP ISO Guide MIX 75Ω Driver NTSC Enc. VSEL Video ISO Gyro, G-sensor TUNER ROM RF PLL CD Core Unit VDD5 VD 8.3V VD2 5.6V 1mA (Max 60mA) 180mA 3.3 ± 0.1V typ 4.5mA 300mA 200mA ( ) 57mA 15mA 11mA 30mA 43mA 28mA 15mA 17mA 2mA p 103mA (Max 140mA) ORA33 yp 172mA (Max 200mA) 0mA (Max 60mA) A (Max 1000mA) typ 200mA 40mA [MEMOLED] 20mA Max 45mA Monitor µ-com [MFLPW] [SWACPW] Touch Panel Remote control sensor Back Light Picture Key LED www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 32 1 2 3 4 1 2 3 4 C D F A B E 3.2 OVERALL CONNECTION DIAGRAM A CC UNIT B G C DVD MECHANISM MODULE (MS3) D E CD MECHANISM MODULE (S10.1AACA) F G SYSTEM UNIT H MONITOR PCB I KEYBOARD PCB J PANEL PCB K L P/S CPU, ASIC, SDRAM GRAPHIC ROM, SRAM, BUS-BUFFER MAIN, CC CORE I/F GPS, SENSOR, VIDEO, I/F 1/6 A 2/6 A 3/6 A 4/6 A 5/6 A 6/6 A AUDIO SYSCOM, VIDEO, I/F P/S 1/3 G 2/3 G 3/3 G W R CON FAN MOTOR TOUCH PANEL LCD PANEL Wir Note: When ordering service parts, be sure to refer to " EXPLODED VIEWS AND PARTS LIST" or "ELECTRICAL PARTS LIST". www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 33 5 6 7 8 5 6 7 8 C D F A B E B GPS UNIT FM/AM TUNER UNIT K CONNECTOR UNIT L MAIN PCB UNIT CORD ASSY CORD ASSY GPS ANTENNA ASSY XM TUNER etc. IP-BUS AV-BUS FM/AM ANTENNA WIRED REMOTE CONTROLLER N OR Wired Remote ANTENNA IN AV IN/OUT POWER SUPPLY EXTERNAL IN/OUT GPS IN IP-BUS IN AV-BUS IN SUB WOOFER and NON FADER OUTPUT www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 34 1 2 3 4 1 2 3 4 C D F A B E 3.3 CC UNIT (P/S) 1/6 A CC UNIT (P/S) 1/6 A 6/6 A 5/6 A > > www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 35 5 6 7 8 5 6 7 8 C D F A B E 1/6 A 2SA1385-ZS1 3/3 G CN1802 Decimal points for resistor and capacitor fixed values are expressed as : 2.2 2R2 0.022 R022 ← ← The > mark found on some component parts indicates the importance of the safety factor of the part. Therefore, when replacing, be sure to use parts of identical designation. Symbol indicates a resistor. No differentiation is made between chip resistors and discrete resistors. NOTE : Symbol indicates a capacitor. No differentiation is made between chip capacitors and discrete capacitors. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 36 1 2 3 4 1 2 3 4 C D F A B E 3.4 CC UNIT (CPU, ASIC, SDRAM)(GUIDE PAGE) A-a 2/6 A 2/6 A-a A-a A-b A-b A-a A-a A-b A-b A-b A-b A-a A-a Large size SCH diagram Guide page Detailed page CC UNIT (CPU, ASIC, SDRAM) 2/6 A 5/6 A 3/6 A www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 37 5 6 7 8 5 6 7 8 C D F A B E A-b 2/6 A 2/6 5/6 A 5/6 A 4/6 A CN601 C www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 38 1 2 3 4 1 2 3 4 C D F A B E A-a A-b A-a A-b 2/6 A-a 2/6 1 CC UNIT (CPU, ASIC, SDRAM) 2/6 A 5/6 A www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 39 5 6 7 8 5 6 7 8 C D F A B E A-a A-b A-a A-b 2/6 A-a 2/6 2 3/6 A www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 40 1 2 3 4 1 2 3 4 C D F A B E A-a A-b A-b 2/6 1 5/6 A CN601 C www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 41 5 6 7 8 5 6 7 8 C D F A B E A-a A-b A-b 2/6 2 4/6 A www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 42 1 2 3 4 1 2 3 4 C D F A B E 3.5 CC UNIT (GRAPHIC)(GUIDE PAGE) A-a 3/6 A 3/6 CC UNIT (GRAPHIC) 3/6 A 4/6 A 2/6 A www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 43 5 6 7 8 5 6 7 8 C D F A B E A-b 3/6 A 3/6 5/6 A www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 44 1 2 3 4 1 2 3 4 C D F A B E A-a A-b A-a A-b 3/6 A-a 3/6 1 CC UNIT (GRAPHIC) 3/6 A 2/6 A www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 45 5 6 7 8 5 6 7 8 C D F A B E A-a A-b A-a A-b 3/6 A-a 3/6 2 3 4/6 A www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 46 1 2 3 4 1 2 3 4 C D F A B E A-a A-b A-b 3/6 1 5/6 A www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 47 5 6 7 8 5 6 7 8 C D F A B E A-a A-b A-b 3/6 2 3 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 48 1 2 3 4 1 2 3 4 C D F A B E 3.6 CC UNIT (ROM, SRAM, BUS-BUFFER) 4/6 A 2/6 A www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 49 5 6 7 8 5 6 7 8 C D F A B E 4/6 A 3/6 A 5/6 A CC UNIT (ROM, SRAM, BUS-BUFFER) 4/6 A www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 50 1 2 3 4 1 2 3 4 C D F A B E 3.7 CC UNIT (MAIN, CC CORE I/F) 5/6 A 2/6 A CC UNIT (MAIN, CC CORE I/F) 5/6 A 4/6 A 3/6 A AUDIO SIGNAL A www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 51 5 6 7 8 5 6 7 8 C D F A B E 5/6 A 6/6 A 1/6 A A A A www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 52 1 2 3 4 1 2 3 4 C D F A B E 3.8 CC UNIT (GPS, SENSOR, VIDEO, I/F) A-a 6/6 A 6/6 CC UNIT (GPS, SENSOR, VIDEO, I/F) 6/6 A 1/6 A 5/6 A H CN5002 > R R S R V S R V S S R V www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 53 5 6 7 8 5 6 7 8 C D F A B E A-b 6/6 A 6/6 CN461 B K CN2804 2/3 G CN1701 V A V V A V V COMPOSIT VIDEO SIGNAL RGB SIGNAL SYNC SIGNAL AUDIO SIGNAL R S A www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 54 1 2 3 4 1 2 3 4 C D F A B E A-a A-b A-a A-b 6/6 A-a 6/6 1 CC UNIT (GPS, SENSOR, VIDEO, I/F) 6/6 A 5/6 A > R www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 55 5 6 7 8 5 6 7 8 C D F A B E A-a A-b A-a A-b 6/6 A-a 6/6 1/6 A H CN5002 R S R V S R V S S R V www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 56 1 2 3 4 1 2 3 4 C D F A B E A-a A-b A-b 6/6 1 CN461 B 2/3 G CN1701 V V A V V COMPOSIT VIDEO SIGNAL RGB SIGNAL SYNC SIGNAL AUDIO SIGNAL R S A www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 57 5 6 7 8 5 6 7 8 C D F A B E A-a A-b A-b 6/6 K CN2804 CN1701 V A www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 58 1 2 3 4 1 2 3 4 C D F A B E 3.9 GPS UNIT (GUIDE PAGE) B-a B GPS ANTENNA CN551 6/6 A www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 59 5 6 7 8 5 6 7 8 C D F A B E B-b B B GPS UNIT www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 60 1 2 3 4 1 2 3 4 C D F A B E A-a B-b B-a B-a B-b 1 2 3 4 5 GPS ANTENNA www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 61 5 6 7 8 5 6 7 8 C D F A B E A-a B-b B-a B-a B-b 6 7 8 CN551 6/6 A www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 62 1 2 3 4 1 2 3 4 C D F A B E B-a B-b B-b 1 2 3 4 5 B GPS UNIT www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 63 5 6 7 8 5 6 7 8 C D F A B E B-a B-b B-b 6 7 8 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 64 1 2 3 4 1 2 3 4 C D F A B E 3.10 DVD CORE UNIT(MS3R)(GUIDE PAGE) C-a C PICKUP UNIT(SERVICE) M3 SPINDLE MOTOR M2 CARRIAGE MOTOR M1 LOADING MOTOR D E sense 4 5 3 2 1 V F F T T T T T F F F CXM1308 CXC4314 CXC4659 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 65 5 6 7 8 5 6 7 8 C D F A B E C-b A B C : The power supply is shown with the marked box. CN2 C DVD CORE UNIT (MS3R) 2/6 A www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 66 1 2 3 4 1 2 3 4 C D F A B E A-a C-b C-a C-a C-b 1 PICKUP UNIT(SERVICE) 1 V F F T T www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 67 5 6 7 8 5 6 7 8 C D F A B E A-a C-b C-a C-a C-b 1 2 M3 SPINDLE MOTOR M2 CARRIAGE MOTOR M1 LOADING MOTOR D E sense 4 5 3 2 CXM1308 CXC4314 CXC4659 T T T F F F www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 68 1 2 3 4 1 2 3 4 C D F A B E C-a C-b C-b 1 CN2 C DVD CORE UNIT (MS3R) 2/6 A www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 69 5 6 7 8 5 6 7 8 C D F A B E C-a C-b C-b 1 2 : The power supply is shown with the marked box. CN2 2/6 A www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 70 1 2 3 4 1 2 3 4 C D F A B E 1 RFOUT 0.2V/div. 0.1µs/div. 0.2V/div. 100µs/div. 0.2V/div. 0.1µs/div. CDRF Interval 1 RFOUT 0.5V/div. 100µs/div. 1 RFOUT DVDRF DVDRF(BD1mm) 2 TD 0.5V/div. 100µs/div. Interval FWD 2 TD 0.5V/div. 100µs/div. Interval REV 2 TD 2 CH1: TD 3 CH2: COP-COM 2.0V/div.5ms/div. Traverse501FWD 0.5V/div.5ms/div. 2 CH1: TD 3 CH2: COP-COM 2.0V/div.5ms/div. Traverse501REV 0.5V/div.5ms/div. 2 CH1: TD 3 CH2: COP-COM 2.0V/div.5ms/div. Traverse5000FWD 0.5V/div.5ms/div. - Waveforms Note:1. The encircled number denote measuring pointes in the circuit diagram. 2. Reference voltage VHALF : 1.65V(TD1,FD1,CRGDRV) : 2V Center(ANAMONI1) In this waveform, it is seeing on the GND standard. Offset of 1.65V or 2V is put in. VHALF→ VHALF→ VHALF→ VHALF→ VHALF→ VHALF→ VHALF→ VHALF→ VHALF→ VHALF→ VHALF→ VHALF→ www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 71 5 6 7 8 5 6 7 8 C D F A B E 2 TD Play TD 5 FD 0.5V/div. 1ms/div. Focus close VHALF→ VHALF→ VHALF→ VHALF→ VHALF→ VHALF→ VHALF→ VHALF→ VHALF→ VHALF→ 0.5V/div. 100µs/div. ID search Insaide → Outside 4 CRGPRV 2 CH1: TD 3 CH2: COP-COM 2.0V/div.5ms/div. Traverse5000REV 0.5V/div.5ms/div. 0.5V/div.20ms/div. 5 FD Focus jamp L 0 → L1 0.5V/div.500µs/div. 2 TD Multi 32REV 0.5V/div.500µs/div. 2 TD Multi 32FWD 0.5V/div.500µs/div. 5 FD Focus jamp L1 → L 0 0.5V/div.500µs/div. 5 FD Play TD 0.5V/div.20ms/div. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 72 1 2 3 4 1 2 3 4 C D F A B E 3.11 COMPOUND UNIT(A) AND COMPOUND UNIT(B) D E E COMPOUND UNIT(B) D COMPOUND UNIT(A) CLAMP S1201 Q1299 S1202 S1204 S1203 R1298 0R0 1 2 3 4 5 6 S1205 R1299 0R0 CPT231SCTD CSN1069 CSN1069 CSN1069 CSN1070 CSN1070 12cm 8cm DISC SENS DISC SENS 8cm CN1202 C C www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 73 5 6 7 8 5 6 7 8 C D F A B E 3.12 PU UNIT(REFERENCE) 24 Iop78 L2 LC Vcc GND GND IC1 L4 C2 C3 C6 C7 L3 17 15 C1 16 65LD 78LD LDGND R1 C5 Short round L1 C4 78LD 65LD 65MD 65MDG VR2/ 65Rmd VR1/ 78Rmd Vmda 1 2 3 4 6 5 7 R2 L6 MDA Top View up MDA A SW Vcc C8 C9 12 GND 13 V r 14 MDC 9 8 78MD 78MDG MDG B1 B1 B2 RF- B3 RF+ B4 C Vref : 2.5V GND C10 TH1 TEMP Vcc SW A NC T- T+ F- F+ B2 RF- B3 RF+ B4 C LDGND 23 26 25 07 08 05 06 22 21 20 19 18 17 27 02 01 03 04 09 16 15 14 13 12 11 10 Iop65 Im/ 2 Im Im/ 2 Ishf Vshf : 4V CN1101 Short round C www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 74 1 2 3 4 1 2 3 4 C D F A B E 3.13 CD MECHANISM MODULE(GUIDE PAGE) F-a F TY PICKUP UNIT(P10)(SERVICE) M1 CXC4440 SPINDLE MOTOR M2 CXB8933 LOADING /CARRIAGE MOTOR CD DRIVER T F F T T T F F F T C S T F S C F F T T S S C C C C S S T T F F 1 3 2 0 9 7 $ 8 5 4 @ # % www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 75 5 6 7 8 5 6 7 8 C D F A B E F-b F ras SRAMLEVEL0 SRAMLEVEL1 SRAMLEVEL2 TYPE_A/D SWITCHES: CD CORE UNIT(S10.1) S901:HOME SWITCH..........ON-OFF S903:DSCSNS SWITCH......ON-OFF S904:12EJ SWITCH.............ON-OFF S905:8EJ SWITCH...............ON-OFF The underlined indicates the switch position. CD CORE UNIT(S10.1) F CN1301 F SIGNAL LINE FOCUS SERVO LINE TRACKING SERVO LINE CARRIAGE SERVO LINE SPINDLE SERVO LINE T C S 3V REGULATOR 3.3V REGULATOR MICRO COMPUTER PE5454B ! ^ & 6 2/3 G www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 76 1 2 3 4 1 2 3 4 C D F A B E A-a F-b F-a F-a F-b 1 2 PICKUP UNIT(P10)(SERVICE) T F F T T T F F F T C S T T F F @ # % www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 77 5 6 7 8 5 6 7 8 C D F A B E A-a F-b F-a F-a F-b 2 3 4 5 6 M1 CXC4440 SPINDLE MOTOR M2 CXB8933 LOADING /CARRIAGE MOTOR CD DRIVER T F S C F F T T S S C C C C S S 1 3 2 0 9 7 $ 8 5 4 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 78 1 2 3 4 1 2 3 4 C D F A B E F-a F-b F-b 1 2 ras SWITCHES: CD CORE UNIT(S10.1) S901:HOME SWITCH..........ON-OFF S903:DSCSNS SWITCH......ON-OFF S904:12EJ SWITCH.............ON-OFF S905:8EJ SWITCH...............ON-OFF The underlined indicates the switch position. CD CORE UNIT(S10.1) F F SIGNAL LINE FOCUS SERVO LINE TRACKING SERVO LINE CARRIAGE SERVO LINE SPINDLE SERVO LINE T C S 3.3V REGULATOR ! www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 79 5 6 7 8 5 6 7 8 C D F A B E F-a F-b F-b 2 3 4 5 6 SRAMLEVEL0 SRAMLEVEL1 SRAMLEVEL2 TYPE_A/D PE5454B CN1301 3V REGULATOR MICRO COMPUTER 2/3 G ^ & 6 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 80 1 2 3 4 1 2 3 4 C D F A B E - Waveforms Note : 1. The encircled numbers denote measuring points in the circuit diagram. 2. Reference voltage REFO1(1.65V) 1 DSCSNS 2 8SNS 3 12SNS 4 LOEJ 5V/div 5V/div 5V/div 5V/div 500ms/div 12 cm CD Loading operation Ref.: GND Mode: Normal 1 DSCSNS 2 8SNS 3 12SNS 4 LOEJ 5V/div 5V/div 5V/div 5V/div 500ms/div Ref.: GND Mode: Normal 1 DSCSNS 5 CLCONT 4 LOEJ 6 VD 5V/div 5V/div 5V/div 10V/div 500ms/div 12 cm CD Loading operation 8 cm CD Loading operation Ref.: GND Mode: Normal 0 FIN ! RFOK 7 SIN 200mV/div 2V/div 2V/div 500ms/div 12 cm CD-DA Source On setup operation Ref.: REFO Mode: Normal # FE 0 FIN @ TE 9 TIN 500mV/div 500mV/div 500mV/div 500mV/div 20ms/div Ref.: REFO Mode: Normal @ TE # FE 500mV/div 500mV/div 200ms/div Source On setup operation CD-DA Play operation Ref.: REFO Mode: Normal # FE 0 FIN @ TE 9 TIN 500mV/div 500mV/div 500mV/div 500mV/div 20ms/div CD-ROM play operation(Regular track Jump) Ref.: REFO Mode: Normal $ MDX 7 SIN 2V/div 1V/div 5µs/div Ref.: REFO Mode: Normal $ MDX 7 SIN 1V/div 200mV/div 50ms/div Spindle waveform during play operation Spindle waveform during play operation (Wider) Ref.: REFO Mode: Normal 7 SIN 8 CIN 9 TIN 1V/div 500mV/div 500mV/div 2s/div 12 cm CD-DA setup operation after loading 12 cm CD-ROM(3 sessions) setup operation after loading Ref.: REFO Mode: Normal 7 SIN 8 CIN 9 TIN 1V/div 500mV/div 500mV/div 2s/div Ref.: REFO Mode: Normal 7 SIN 8 CIN 9 TIN 1V/div 500mV/div 500mV/div 1s/div 12 cm CD-ROM(1 session) setup operation after loading Ref.: REFO Mode: Normal www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 81 5 6 7 8 5 6 7 8 C D F A B E 0 FIN # FE 500mV/div 500mV/div 200ms/div Focus Search waveform Ref.: REFO Mode: TEST % RFAGC @ TE 9 TIN 1V/div 500mV/div 500mV/div 500µs/div Ref.: REFO Mode: TEST @ TE % RFAGC 500mV/div 500mV/div 2ms/div Track Open waveform 1 Track Jump waveform Ref.: REFO Mode: TEST % RFAGC @ TE 8 CIN 7 SIN 1V/div 1V/div 500mV/div 2V/div 200ms/div Ref.: REFO Mode: Normal Search operation(Outter to Inner) ^ LOUT & ROUT 1V/div 1V/div 200µs/div Analog audio waveform Ref.: AGND Mode: Normal 7 SIN 8 CIN 9 TIN 1V/div 500mV/div 500mV/div 500ms/div Ref.: REFO Mode: Normal 1 DSCSNS 2 8SNS 3 12SNS 4 LOEJ 5V/div 5V/div 5V/div 5V/div 500ms/div 12 cm CD Eject operation CD-DA >> CD-ROM mode change(Band key) Ref.: GND Mode: Normal % RFAGC @ TE 9 TIN 1V/div 500mV/div 500mV/div 500µs/div 4 Tracks Jump waveform 32 Tracks Jump waveform Ref.: REFO Mode: TEST % RFAGC @ TE 9 TIN 1V/div 500mV/div 500mV/div 2ms/div Ref.: REFO Mode: TEST % RFAGC @ TE 9 TIN 1V/div 500mV/div 500mV/div 1ms/div 10 Tracks Jump waveform Ref.: REFO Mode: TEST 1 DSCSNS 5 CLCONT 4 LOEJ 5V/div 5V/div 5V/div 500ms/div 12 cm CD Eject operation Ref.: GND Mode: Normal 1 DSCSNS 2 8SNS 3 12SNS 4 LOEJ 5V/div 5V/div 5V/div 5V/div 500ms/div 8 cm CD Eject operation Ref.: GND Mode: Normal www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 82 1 2 3 4 1 2 3 4 C D F A B E 7 SIN 8 CIN 9 TIN 1V/div 500mV/div 500mV/div 500ms/div CD-ROM >> CD-DA mode change(Band key) Ref.: REFO Mode: Normal % RFAGC 9 TIN @ TE 0 FIN 1V/div 1V/div 1V/div 1V/div 500µs/div Black dot(800µm) during play Ref.: REFO Mode: Normal www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 83 5 6 7 8 5 6 7 8 C D F A B E www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 84 1 2 3 4 1 2 3 4 C D F A B E 3.14 SYSTEM UNIT (AUDIO) 1/3 G 2/3 G 3/3 G 2/3 G 2/3 G A A A A A A A A A A A A A A www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 85 5 6 7 8 5 6 7 8 C D F A B E 1/3 G 1/3 G SYSTEM UNIT (AUDIO) 2/3 G 3/3 G A A A A A A A A A A A A A A A A A A A A AUDIO SIGNAL www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 86 1 2 3 4 1 2 3 4 C D F A B E 3.15 SYSTEM UNIT (SYSCOM, VIDEO, I/F)(GUIDE PAGE) G-a 2/3 G 2/3 1/3 G CN605 6/6 A SYSTEM CONTROLLER A A A A A A V V A V V V V V V V V V V V V V V V V www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 87 5 6 7 8 5 6 7 8 C D F A B E G-b 2/3 G 2/3 > > 3/3 G J CN5901 F CN901 2/3 G SYSTEM UNIT (SYSCOM, VIDEO, I/F) EM CONTROLLER A A A A A A A A V V V V V V V A A V COMPOSIT VIDEO SIGNAL AUDIO SIGNAL A www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 88 1 2 3 4 1 2 3 4 C D F A B E A-a G-b G-a G-b 2/3 G-a 2/3 1 2 1/3 G A A A A A V V V V V V V V V V V V V V V www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 89 5 6 7 8 5 6 7 8 C D F A B E A-a G-b G-a G-b 2/3 G-a 2/3 3 CN605 6/6 A SYSTEM CONTROLLER A V V A V www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 90 1 2 3 4 1 2 3 4 C D F A B E G-a G-b G-b 2/3 1 2 > > J CN5901 F CN901 2/3 G SYSTEM UNIT (SYSCOM, VIDEO, I/F) A A A A A A A V V V V V V A A V COMPOSIT VIDEO SIGNAL AUDIO SIGNAL A www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 91 5 6 7 8 5 6 7 8 C D F A B E G-a G-b G-b 2/3 3 3/3 G ONTROLLER www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 92 1 2 3 4 1 2 3 4 C D F A B E 3.16 SYSTEM UNIT (P/S) 3/3 G 1/3 G 2/3 G > > > > > > 1/6 A CN801 A A www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 93 5 6 7 8 5 6 7 8 C D F A B E 3/3 G PTZ27(B) PTZ27(B) 3/3 G SYSTEM UNIT (P/S) > > > FAN MOTOR CXM1320 A AUDIO SIGNAL A A www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 94 1 2 3 4 1 2 3 4 C D F A B E 3.17 MONITOR PCB (GUIDE PAGE) H-a H : The power supply is shown with the marked box. POWER SUPPLY DIMMER S TEMPERATURE SENSOR CN701 Monitor Adjustment PCB(GGF1416) R V S V 1 2 3 4 5 6 7 8 ! ⁄ ¤ ) ( 6/6 A www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 95 5 6 7 8 5 6 7 8 C D F A B E H-b H DIMMER P in P IC TFT Controller Video Multi Processing P in P Y/C Separation OSD Interface H MONITOR PCB MONI_PANEL UNIT Consists of MONITOR PCB KEYBOARD PCB PANEL PCB LCD PANEL TOUCH PANEL I CN5700 LCD PANEL R R R R V S : RGB Signal : Sync Signal : Composite Video Signal R S V 5 6 7 0 9 @ # $ % ^ & * www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 96 1 2 3 4 1 2 3 4 C D F A B E A-a H-b H-a H-a H-b POWER SUPPLY DIMMER TEMPERATURE SENSOR V 1 2 3 4 5 6 ( www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 97 5 6 7 8 5 6 7 8 C D F A B E A-a H-b H-a H-a H-b 1 2 3 : The power supply is shown with the marked box. CN701 Monitor Adjustment PCB(GGF1416) R V S 8 ! ⁄ ¤ ) 6/6 A www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 98 1 2 3 4 1 2 3 4 C D F A B E H-a H-b H-b IMMER P in P IC H MONITOR PCB MONI_PANEL UNIT Consists of MONITOR PCB KEYBOARD PCB PANEL PCB LCD PANEL TOUCH PANEL I CN R S 5 6 7 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 99 5 6 7 8 5 6 7 8 C D F A B E H-a H-b H-b 1 2 3 P in P IC TFT Controller Video Multi Processing P in P Y/C Separation OSD Interface I CN5700 LCD PANEL R R R V : RGB Signal : Sync Signal : Composite Video Signal R S V 0 9 @ # $ % ^ & * www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 100 1 2 3 4 1 2 3 4 C D F A B E - Waveforms The encircled number denote measuring pointes in the circuit diagram. 8 CH1 : ANG 9 CH2 : GOUT 0 CH3 : VG 1 CH1 : IC5851 Pin 10 2 CH2 : IC5851 Pin 7 3 CH3 : IC5851 Pin 38 4 CH4 : IC5851 Pin 47 5 CH1 : IC5901 Pin 2 6 CH2 : IC5901 Pin 6 7 CH3 : IC5901 Pin 7 ! CH1 : CSYNC0 @ CH2 : CVBS2 9 CH3 : GOUT 0 CH4 : VG ! CH1 : CSYNC0 # CH2 : POL $ CH3 : VCOM 0 CH4 : VG ! CH1 : CSYNC0 % CH2 : CX ^ CH3 : STH1 0 CH4 : VG www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 101 5 6 7 8 5 6 7 8 C D F A B E ( CH1 : V33 ) CH2 : PIPRES ⁄ CH3 : PIPCK ¤ CH4 : PIPDA ! CH1 : CSYNC0 % CH2 : CX & CH3 : STV1 0 CH4 : VG ! CH1 : CSYNC0 * CH2 : CPH 0 CH3 : VG ( CH1 : V33 ) CH2 : PIPRES ⁄ CH3 : PIPCK ¤ CH4 : PIPDA www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 102 1 2 3 4 1 2 3 4 C D F A B E 3.18 KEYBOARD PCB I P. AD I KEYBOARD PCB H CN5008 MONI_PANEL UNIT Consists of MONITOR PCB KEYBOARD PCB PANEL PCB SELECT www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 103 5 6 7 8 5 6 7 8 C D F A B E I P. ADJ www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 104 1 2 3 4 1 2 3 4 C D F A B E 3.19 PANEL PCB J G CN1651 J PANEL PCB MONI_PANEL UNIT Consists of MONITOR PCB KEYBOARD PCB PANEL PCB CD EJECT DVD EJECT www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 105 5 6 7 8 5 6 7 8 C D F A B E www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 106 1 2 3 4 1 2 3 4 C D F A B E 3.20 CONNECTOR UNIT K L CN2 6/6 A CN702 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 107 5 6 7 8 5 6 7 8 C D F A B E K K CONNECTOR UNIT > www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 108 1 2 3 4 1 2 3 4 C D F A B E 3.21 MAIN PCB UNIT L CEK1304 CZC5169 HZU6R2(B2) K CN2806 MAIN PCB UNIT M10 CZX5102 (FLAP) > M HOME SW OPEN SW (2A) L 1 2 4 3 7 56 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 109 5 6 7 8 5 6 7 8 C D F A B E - Waveforms The encircled number denote measuring pointes in the circuit diagram. • FULL OPEN • HALF OPEN • CLOSE 1 CH1 : OPENSW 2 CH2 : PULSE1 3 CH3 : MOT0 4 CH4 : MOT1 5 CH1 : HALFSW 2 CH2 : PULSE1 3 CH3 : MOT0 4 CH4 : MOT1 6 CH1 : HOMESW 2 CH2 : PULSE1 3 CH3 : MOT0 4 CH4 : MOT1 • ANGLE 7 CH1 : PULSE0 2 CH2 : PULSE1 3 CH3 : MOT0 4 CH4 : MOT1 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 110 1 2 3 4 1 2 3 4 C D F A B E 4. PCB CONNECTION DIAGRAM 4.1 CC UNIT Capacitor Connector P.C.Board Chip Part A A CC UNIT SIDE B SIDE A NOTE FOR PCB DIAGRAMS 1.The parts mounted on this PCB include all necessary parts for several destination. For further information for respective destinations, be sure to check with the schematic dia- gram. 2.Viewpoint of PCB diagrams 10 20 30 40 50 60 7 10 20 30 40 50 60 70 80 90 100 110 120 130 140 0 X Y B CN461 C CN601 G CN1701 H CN5002 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 111 5 6 7 8 5 6 7 8 C D F A B E A SIDE A 60 70 80 90 100 110 120 130 140 150 160 170 G CN1802 FRONT K CN2804 EXTERNAL IN/OUT www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 112 1 2 3 4 1 2 3 4 C D F A B E A A CC UNIT 90 100 110 120 130 140 150 160 170 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 113 5 6 7 8 5 6 7 8 C D F A B E A SIDE B 10 20 30 40 50 60 70 80 90 10 20 30 40 50 60 70 80 90 100 110 120 130 140 0 X Y www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 114 1 2 3 4 1 2 3 4 C D F A B E 4.2 GPS UNIT B B GPS UNIT SIDE A 0 10 20 30 40 50 60 10 20 30 X Y CN551 GPS ANTENNA ASSY A www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 115 5 6 7 8 5 6 7 8 C D F A B E B B GPS UNIT SIDE B 0 60 50 40 30 20 10 10 20 30 X Y www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 116 1 2 3 4 1 2 3 4 C D F A B E 4.3 DVD CORE UNIT(MS3R) C C DVD CORE UNIT (MS3R) 0 10 20 30 40 50 0 10 20 30 40 50 X Y A CN2 GND1 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 117 5 6 7 8 5 6 7 8 C D F A B E C SIDE A 50 60 70 80 90 100 PICKUP UNIT (SERVICE) M2 M3 E M1 RFOUT www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 118 1 2 3 4 1 2 3 4 C D F A B E C C DVD CORE UNIT (MS3R) 60 70 80 90 100 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 119 5 6 7 8 5 6 7 8 C D F A B E C SIDE B 0 10 20 30 40 50 0 10 20 30 40 50 X Y D www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 120 1 2 3 4 1 2 3 4 C D F A B E 4.4 COMPOUND UNIT(A) AND COMPOUND UNIT(B) COMPOUND UNIT(B) D E E COMPOUND UNIT(A) D 12cm S1201 R1298 R1299 Q1299 1 6 DISC SENS S1204 DISC SENS S1203 8cm S1202 8cm S1205 C C CLAMP CN1202 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 121 5 6 7 8 5 6 7 8 C D F A B E www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 122 1 2 3 4 1 2 3 4 C D F A B E 4.5 CD CORE UNIT(S10.1) F F CD CORE UNIT(S10.1) SIDE A G CN1301 PICKUP UNIT(P10)(SERVICE) HOME M2 LOADING /CARRIAGE MOTOR M1 SPINDLE MOTOR E F REFO1 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 123 5 6 7 8 5 6 7 8 C D F A B E F F CD CORE UNIT(S10.1) SIDE B 12EJ 8EJ DSCSNS www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 124 1 2 3 4 1 2 3 4 C D F A B E 4.6 SYSTEM UNIT G G SYSTEM UNIT 10 20 30 40 50 60 70 80 0 X 10 20 30 40 50 60 70 80 90 100 110 120 Y FRONT AV IN/OUT POWER SUPPLY J CN5901 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 125 5 6 7 8 5 6 7 8 C D F A B E G SIDE A 80 90 100 110 120 130 140 150 160 170 F CN901 FRONT WIRED REMOTE CONTROLLER FAN MOTOR FM/AM ANTENNA FM/AM TUNER UNIT www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 126 1 2 3 4 1 2 3 4 C D F A B E G G SYSTEM UNIT 80 90 100 110 120 130 140 150 160 170 A CN801 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 127 5 6 7 8 5 6 7 8 C D F A B E G SIDE B 10 20 30 40 50 60 70 80 0 X 10 20 30 40 50 60 70 80 90 100 110 120 Y A CN605 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 128 1 2 3 4 1 2 3 4 C D F A B E 4.7 MONITOR PCB H H MONITOR PCB FRONT LCD PANEL TOUCH PANEL www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 129 5 6 7 8 5 6 7 8 C D F A B E H SIDE A A CN701 FRONT I CN5700 LCD PANEL www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 130 1 2 3 4 1 2 3 4 C D F A B E H H MONITOR PCB www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 131 5 6 7 8 5 6 7 8 C D F A B E H SIDE B www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 132 1 2 3 4 1 2 3 4 C D F A B E 4.8 KEYBOARD PCB I I KEYBOARD PCB SIDE A MAP AV VOL- VOL+ SRC OPEN ANGLE INFO DEST TRFC P.ADJ MEMO RESET SELECT www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 133 5 6 7 8 5 6 7 8 C D F A B E I I KEYBOARD PCB SIDE B H CN5008 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 134 1 2 3 4 1 2 3 4 C D F A B E 4.9 PANEL PCB J J PANEL PCB J PANEL PCB SIDE A SIDE B G CN1651 CD EJECT DVD EJECT www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 135 5 6 7 8 5 6 7 8 C D F A B E www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 136 1 2 3 4 1 2 3 4 C D F A B E 4.10 CONNECTOR UNIT K K CONNECTOR UNIT SIDE A 10 20 30 40 50 60 70 10 20 30 0 X Y A CN702 L CN2 AV-BUS IN IP-BUS IN www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 137 5 6 7 8 5 6 7 8 C D F A B E K K CONNECTOR UNIT SIDE B 70 60 50 40 30 20 10 10 20 30 0 X Y www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 138 1 2 3 4 1 2 3 4 C D F A B E 4.11 MAIN PCB UNIT MAIN PCB UNIT L L E Q1 C3 C1 C4 C14 C13 C8 C9 C10 R3 R1 R4 R5 R11 R17 R16 R21 R19 R20 R14 R13 R22 R9 R8 R6 R7 R2 R18 C2 C11 C12 C7 IC3 1 4 5 8 1 IC2 1 9 16 8 L2 D10 D9 D8 D7 D4 D3 D6 D5 D1 D2 1 2 15 14 5 10 CN2 1 2 CN1 L1 Q4 FU1 E Q3 S2 S1 S3 Q2 IC1 IC,Q Q1 Q2 Q4 Q3 IC1 IC2 IC3 1 2 3 6 5 4 1 2 3 6 5 4 2 3 4 5 OPEN HOME HALF R15 R12 C6 R10 K CN2806 M10 (FLAP) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 139 5 6 7 8 5 6 7 8 C D F A B E MAIN PCB UNIT L L IC,Q IC4 IC5 IC4 A E C K IC5 A E C K www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 140 1 2 3 4 1 2 3 4 C D F A B E 5. ELECTRICAL PARTS LIST NOTE: • Parts whose parts numbers are omitted are subject to being not supplied. • The part numbers shown below indicate chip components. Chip Resistor RS1/_S___J,RS1/__S___J Chip Capacitor (except for CQS.....) CKS....., CCS....., CSZS..... • The > mark found on some component parts indicates the importance of the safety factor of the part. Therefore, when replacing, be sure to use parts of identical designation. • Meaning of the figures and others in the parentheses in the parts list. Example) IC 301 is on the point (face A, 91 of x-axis, and 111 of y-axis) of the corresponding PC board. IC 301 (A, 91, 111) IC NJM2068V Circuit Symbol and No. Part No. A Unit Number:CWM9919 Unit Name:CC Unit MISCELLANEOUS IC 1 (B,135,39) IC K4S561632E-TL75 IC 2 (A,137,59) IC UPD705103GM-180S1 IC 3 (B,151,39) IC HY57V561620CLT-H IC 4 (A,154,29) IC TC7SZ08FU IC 5 (B,143,63) IC PD6336C IC 101 (A,131,26) IC TC74LCX08FTS1 IC 102 (A,133,20) IC TC7SH04FUS1 IC 103 (A,131,36) IC TC74LCX245FTS1 IC 104 (A,139,36) IC TC74LCX245FTS1 IC 105 (A,148,36) IC TC74LCX245FTS1 IC 106 (A,156,36) IC TC74LCX245FTS1 IC 107 (A,159,46) IC TC74LCX541FTS1 IC 108 (A,159,54) IC TC74LCX541FTS1 IC 109 (A,159,63) IC TC74LCX541FTS1 IC 110 (B,114,48) IC PEH007A IC 111 (B,114,32) IC PEH008A IC 112 (B,103,70) IC TC7SH00FUS1 IC 113 (B,115,66) IC M5M5V216ATP-70HI IC 114 (B,103,67) IC TC7SH08FUS1 IC 201 (A,101,33) IC MB86291APFVS-G-DL IC 301 (A,140,27) IC M51957BFP IC 302 (A,138,19) IC TC7SH08FUS1 IC 304 (A,105,61) IC AK4351VT IC 309 (A,117,57) IC TC7SH08FUS1 IC 551 (B,13,72) IC NJM2904M IC 602 (A,114,8) IC TC7SH14FUS1 IC 651 (A,155,120) IC UPD4721GSS1 IC 751 (B,40,115) IC TC7SH08FUS1 IC 752 (B,42,103) IC BH7236AF IC 753 (A,43,110) IC TC7SH08FUS1 IC 801 (B,91,94) IC BA25BC0WFP IC 802 (B,102,91) IC S-818A33AUC-BGN IC 803 (B,59,32) IC TPS5103IDB IC 804 (B,62,67) IC TPS5102IDBT Q 201 (A,122,19) Transistor UMD2N Q 301 (A,146,30) Transistor DTC114EU Q 551 (A,19,126) Transistor DTC114EU Q 552 (A,26,129) Transistor 2SA1576 Q 553 (B,18,80) Transistor DTC114WK Q 554 (B,20,34) Transistor DTC114EU Q 601 (A,122,114) Transistor IMD2A Q 603 (A,104,8) Transistor 2SA1576 Q 604 (A,100,8) Transistor 2SC4081 Q 651 (B,164,123) Transistor IMD3A Q 652 (B,159,128) Transistor 2SD1767 Q 751 (B,28,117) Transistor 2SA1576 Q 752 (B,28,112) Transistor 2SA1576 Q 753 (B,28,107) Transistor 2SA1576 Q 754 (B,28,97) Transistor 2SA1576 Q 801 (A,90,61) Transistor 2SB1184F5 Q 802 (A,90,71) Transistor DTC114EU Q 803 (B,70,50) Transistor DTC114EU Q 804 (B,68,28) Transistor DTC114EU Q 805 (B,57,53) Transistor DTC114EU Q 806 (B,159,104) Transistor UMF23N Q 807 (B,75,57) FET RK4936 Q 808 (B,75,76) FET RK4936 Q 809 (B,153,98) Transistor 2SD1760F5 Q 811 (B,46,35) FET RK4936 Q 813 (B,23,18) Transistor 2SA1385-ZS1 Q 814 (B,21,11) Transistor DTC114EU D 551 (A,20,128) Diode UDZS5R6(B) D 552 (A,21,54) Diode 1SS355 D 601 (A,109,7) Diode 1SS355 D 602 (A,94,5) Diode 1SS355 D 603 (A,93,8) Diode 1SS355 D 604 (A,118,9) Diode UDZS5R6(B) D 651 (B,150,136) Diode UDZS6R8(B) D 652 (B,154,136) Diode UDZS20(B) D 653 (B,154,140) Diode UDZS20(B) D 654 (B,148,136) Diode UDZS20(B) D 655 (B,148,140) Diode UDZS20(B) D 656 (B,152,136) Diode UDZS20(B) D 657 (B,152,140) Diode UDZS20(B) Circuit Symbol and No. Part No. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 141 5 6 7 8 5 6 7 8 C D F A B E D 658 (B,146,136) Diode UDZS20(B) D 659 (B,146,140) Diode UDZS20(B) D 660 (B,165,127) Diode HZU8R2(B1) D 801 (B,55,38) Diode RB400D D 802 (B,69,65) Diode RB400D D 803 (B,69,68) Diode RB400D D 806 (A,71,63) Diode RB060L-40 D 807 (A,71,68) Diode RB060L-40 D 810 (A,47,27) Diode RB060L-40 L 1 (B,127,25) Inductor CTF1558 L 2 (B,142,26) Inductor CTF1558 L 3 (A,154,25) Inductor CTF1410 L 5 (A,135,41) Inductor CTF1556 L 6 (A,123,42) Inductor CTF1295 L 7 (B,157,63) Inductor CTF1558 L 8 (A,144,76) Inductor CTF1556 L 9 (B,40,49) Inductor CTF1453 L 10 (A,39,54) Inductor CTF1463 L 11 (A,128,88) Inductor CTF1306 L 101 (A,128,24) Inductor CTF1557 L 102 (A,129,20) Inductor CTF1557 L 103 (A,135,36) Inductor CTF1557 L 104 (A,144,35) Inductor CTF1557 L 105 (A,152,35) Inductor CTF1557 L 106 (A,160,35) Inductor CTF1557 L 107 (A,159,42) Inductor CTF1557 L 108 (A,159,50) Inductor CTF1557 L 109 (A,159,59) Inductor CTF1557 L 110 (B,102,46) Inductor CTF1556 L 111 (B,102,31) Inductor CTF1556 L 112 (B,103,63) Inductor CTF1556 L 113 (B,105,68) Inductor CTF1557 L 114 (B,105,63) Inductor CTF1557 L 201 (A,122,37) Inductor CTF1556 L 203 (A,82,18) Inductor CTF1556 L 204 (A,101,53) Inductor CTF1488 L 205 (A,119,29) Inductor CTF1556 L 206 (A,85,53) Inductor CTF1556 L 207 (A,91,51) Inductor CTF1379 L 301 (A,137,27) Inductor CTF1557 L 302 (A,140,21) Inductor CTF1557 L 305 (A,98,62) Inductor CTF1556 L 312 (A,117,60) Inductor CTF1410 L 552 (A,38,138) Inductor CTF1334 L 553 (A,19,93) Inductor CTF1334 L 554 (A,19,95) Inductor CTF1334 L 555 (A,21,96) Inductor CTF1334 L 556 (A,21,98) Inductor CTF1463 L 557 (A,18,100) Inductor CTF1463 L 558 (A,21,103) Inductor CTF1463 L 559 (B,18,126) Inductor CTF1334 L 601 (A,117,90) Inductor CTF1334 L 602 (A,116,93) Inductor CTF1306 L 603 (A,116,90) Inductor CTF1306 L 604 (A,113,93) Inductor CTF1334 L 605 (A,114,90) Inductor CTF1334 L 606 (A,112,88) Inductor CTF1378 L 607 (A,110,88) Inductor CTF1378 L 608 (A,109,88) Inductor CTF1378 L 609 (A,105,88) Inductor CTF1378 Circuit Symbol and No. Part No. L 610 (A,126,91) Inductor CTF1306 L 611 (A,128,91) Inductor CTF1306 L 612 (A,126,88) Inductor CTF1384 L 613 (A,125,91) Inductor CTF1387 L 614 (A,125,88) Inductor CTF1334 L 615 (A,129,94) Inductor CTF1334 L 616 (A,96,79) Inductor CTF1306 L 617 (A,123,88) Inductor CTF1306 L 618 (A,123,91) Inductor CTF1306 L 619 (A,122,89) Inductor CTF1334 L 620 (A,120,92) Inductor CTF1334 L 621 (A,119,92) Inductor CTF1334 L 622 (A,119,89) Inductor CTF1334 L 623 (A,122,92) Inductor CTF1306 L 624 (A,103,88) Inductor CTF1334 L 625 (A,117,93) Inductor CTF1306 L 626 (A,130,88) Inductor CTF1306 L 628 (A,31,17) Inductor CTF1306 L 629 (A,28,15) Inductor CTF1306 L 630 (A,31,15) Inductor CTF1306 L 631 (A,28,22) Inductor CTF1334 L 632 (A,119,113) Inductor CTF1334 L 633 (A,29,20) Inductor CTF1334 L 634 (A,111,5) Inductor CTF1334 L 635 (A,25,15) Inductor CTF1306 L 636 (A,28,17) Inductor CTF1378 L 637 (A,112,91) Inductor CTF1306 L 638 (A,29,13) Inductor CTF1306 L 651 (A,148,116) Inductor CTF1410 L 653 (B,154,125) Inductor CTF1334 L 654 (B,149,125) Inductor CTF1334 L 655 (B,152,125) Inductor CTF1334 L 656 (B,147,125) Inductor CTF1334 L 657 (A,151,126) Inductor CTF1463 L 701 (A,72,13) Inductor CTF1306 L 702 (A,71,14) Inductor CTF1306 L 703 (A,69,14) Inductor CTF1306 L 704 (A,68,14) Inductor CTF1334 L 705 (A,66,14) Inductor CTF1334 L 706 (A,65,14) Inductor CTF1384 L 707 (A,64,10) Inductor CTF1357 L 708 (A,74,103) Inductor CTF1306 L 709 (A,76,103) Inductor CTF1306 L 710 (A,77,103) Inductor CTF1306 L 711 (A,79,103) Inductor CTF1306 L 712 (A,80,103) Inductor CTF1306 L 713 (A,82,103) Inductor CTF1306 L 714 (A,83,103) Inductor CTF1306 L 715 (A,80,101) Inductor CTF1306 L 716 (A,90,103) Inductor CTF1629 L 717 (A,89,100) Inductor CTF1384 L 751 (A,44,103) Inductor CTF1334 L 752 (B,46,116) Inductor CTF1334 L 753 (B,32,101) Inductor LCTAW680J3225 L 754 (A,47,108) Inductor CTF1334 L 755 (B,36,117) Inductor CTF1357 L 756 (A,40,109) Inductor CTF1357 L 801 (A,134,90) Inductor CTF1463 L 802 (B,106,89) Inductor CTF1463 L 803 (A,68,91) Inductor CTF1306 Circuit Symbol and No. Part No. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 142 1 2 3 4 1 2 3 4 C D F A B E L 804 (A,62,87) Inductor CTF1463 L 805 (A,72,76) Inductor CTH1257 L 807 (A,48,35) Inductor CTH1254 L 808 (A,64,34) Inductor CTH1257 L 809 (A,59,73) Inductor CTH1253 L 810 (A,71,56) Inductor CTH1257 L 811 (A,60,80) Inductor CTF1453 L 814 (B,73,89) Inductor CTF1453 L 815 (A,25,35) Inductor CTH1262 TH601 (A,124,117) Thermistor CCX1056 X 1 (A,139,80) Radiator 30.000MHz CSS1633 X 2 (B,130,69) Radiator 33.000MHz CSS1634 X 3 (B,157,57) Radiator 33.86MHz CSS1551 X 202 (A,122,29) Radiator 14.31818MHz CSS1632 >FU651 (A,154,126) Fuse 1A CEK1280 >FU802 (A,80,55) Fuse 2.5A CEK1285 >FU803 (A,81,79) Fuse 1A CEK1280 GY551 (A,48,138) Sensor CSX1054 GY554 (A,24,138) Sensor CSX1089 RESISTORS R 1 (B,126,42) RS1/16S0R0J R 3 (B,126,45) RS1/16S0R0J R 6 (A,117,71) RS1/16S473J R 7 (A,152,56) RS1/16S220J R 8 (A,116,78) RS1/16S473J R 10 (A,148,78) RS1/16S104J R 11 (A,151,78) RAB4C473J R 12 (A,141,75) RS1/16S105J R 13 (A,139,75) RS1/16S151J R 14 (B,143,42) RS1/16S0R0J R 16 (B,143,45) RS1/16S0R0J R 19 (A,117,76) RS1/16S473J R 20 (A,131,77) RS1/16S101J R 21 (A,134,74) RS1/16S101J R 22 (A,132,77) RS1/16S101J R 23 (B,133,68) RS1/16S105J R 24 (B,133,70) RS1/16S151J R 25 (A,130,77) RS1/16S101J R 26 (A,134,77) RS1/16S101J R 27 (A,130,74) RS1/16S101J R 28 (A,133,74) RS1/16S101J R 29 (A,129,74) RS1/16S101J R 30 (A,128,74) RS1/16S101J R 31 (A,128,77) RS1/16S101J R 32 (B,133,61) RS1/16S473J R 33 (A,127,77) RS1/16S473J R 34 (B,154,58) RS1/16S105J R 35 (A,123,57) RS1/16S104J R 36 (A,122,67) RS1/16S101J R 37 (A,122,68) RS1/16S101J R 38 (A,122,70) RS1/16S101J R 39 (A,122,71) RS1/16S101J R 40 (A,121,54) RS1/16S470J R 45 (B,126,64) RS1/16S104J R 46 (B,126,69) RS1/16S104J R 47 (B,156,55) RS1/16S104J R 48 (B,155,73) RS1/16S104J R 49 (B,156,73) RS1/16S104J Circuit Symbol and No. Part No. R 50 (B,158,73) RS1/16S104J R 51 (A,49,66) RS1/16SS0R0J R 52 (A,49,62) RS1/16SS101J R 53 (A,49,64) RS1/16SS101J R 54 (A,73,49) RS1/16SS101J R 55 (A,72,49) RS1/16SS101J R 56 (A,71,49) RS1/16SS101J R 57 (A,70,49) RS1/16SS101J R 58 (A,69,49) RS1/16SS101J R 59 (A,68,49) RS1/16SS101J R 60 (A,67,49) RS1/16SS101J R 61 (A,66,49) RS1/16SS101J R 62 (A,65,49) RS1/16SS101J R 63 (A,64,49) RS1/16SS101J R 64 (A,63,49) RS1/16SS101J R 65 (A,62,49) RS1/16SS101J R 66 (A,61,49) RS1/16SS101J R 67 (A,60,49) RS1/16SS101J R 68 (A,59,49) RS1/16SS101J R 69 (A,58,49) RS1/16SS101J R 70 (A,56,49) RS1/16SS101J R 71 (B,80,41) RS1/16SS101J R 72 (B,80,45) RS1/16SS101J R 73 (B,80,38) RS1/16SS101J R 74 (B,80,39) RS1/16SS101J R 75 (B,80,37) RS1/16SS101J R 76 (B,80,36) RS1/16SS101J R 77 (B,80,33) RS1/16SS101J R 78 (B,80,34) RS1/16SS101J R 79 (A,57,49) RS1/16SS101J R 80 (A,55,49) RS1/16SS101J R 81 (A,54,49) RS1/16SS101J R 84 (B,80,44) RS1/16SS562J R 85 (B,80,35) RS1/16SS103J R 87 (B,156,71) RS1/16S104J R 88 (B,128,57) RS1/16S104J R 89 (B,132,54) RS1/16S0R0J R 90 (B,132,53) RS1/16S0R0J R 93 (B,130,52) RS1/16S153J R 94 (B,134,52) RS1/16S153J R 95 (B,130,57) RS1/16S153J R 96 (B,130,56) RS1/16S153J R 97 (A,118,64) RS1/16S473J R 98 (A,155,69) RS1/16S473J R 101 (B,102,44) RS1/16S473J R 102 (B,102,29) RS1/16S473J R 103 (B,101,67) RS1/16S473J R 104 (A,131,31) RS1/16S220J R 151 (B,126,41) RS1/16S0R0J R 152 (B,158,43) RS1/16S0R0J R 153 (B,142,52) RS1/16S471J R 154 (A,116,64) RS1/16S473J R 155 (A,113,64) RS1/16S473J R 156 (A,105,74) RS1/16S473J R 158 (A,118,60) RS1/16S473J R 159 (B,126,65) RS1/16S473J R 160 (A,119,69) RS1/16S473J R 161 (A,105,77) RS1/16S473J R 162 (B,131,65) RS1/16S473J R 163 (A,122,66) RS1/16S560J Circuit Symbol and No. Part No. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 143 5 6 7 8 5 6 7 8 C D F A B E R 164 (A,112,74) RS1/16S473J R 165 (A,122,78) RS1/16S473J R 166 (A,104,77) RS1/16S473J R 167 (A,117,72) RS1/16S473J R 170 (A,107,74) RS1/16S473J R 171 (A,109,74) RS1/16S473J R 172 (A,108,74) RS1/16S473J R 174 (A,122,75) RS1/16S473J R 175 (A,122,76) RS1/16S473J R 176 (A,122,65) RS1/16S0R0J R 177 (A,117,74) RS1/16S473J R 178 (A,117,75) RS1/16S473J R 179 (A,110,71) RS1/16S473J R 180 (A,145,74) RS1/16S101J R 181 (A,114,64) RS1/16S473J R 183 (A,114,71) RS1/16S473J R 184 (A,114,67) RS1/16S473J R 185 (A,112,71) RS1/16S473J R 186 (A,113,67) RS1/16S473J R 187 (A,112,67) RS1/16S473J R 188 (A,107,77) RS1/16S473J R 189 (A,108,77) RS1/16S473J R 190 (A,109,77) RS1/16S473J R 191 (B,126,72) RS1/16S473J R 192 (A,113,71) RS1/16S473J R 193 (A,123,74) RS1/16S473J R 194 (A,146,76) RS1/16S390J R 196 (A,112,77) RS1/16S473J R 198 (A,124,72) RS1/16SS473J R 199 (A,117,81) RS1/16SS473J R 201 (A,120,49) RN1/16SE1502D R 202 (A,120,48) RN1/16SE1202D R 210 (A,98,51) RS1/16S104J R 211 (A,97,51) RS1/16S104J R 212 (A,90,51) RS1/16S104J R 213 (A,88,51) RS1/16S104J R 217 (A,121,44) RS1/16S272J R 220 (A,122,16) RS1/16S223J R 221 (A,121,34) RS1/16S105J R 222 (A,122,25) RS1/16S151J R 224 (A,79,24) RS1/16S0R0J R 225 (A,117,17) RS1/16S104J R 226 (A,118,17) RS1/16S104J R 227 (A,79,27) RS1/16S104J R 228 (A,80,27) RS1/16S104J R 229 (B,115,25) RS1/16S560J R 230 (A,80,22) RS1/16S104J R 232 (A,82,22) RS1/16S104J R 237 (B,112,25) RS1/16S104J R 238 (B,114,25) RS1/16S330J R 240 (A,114,16) RS1/16S104J R 301 (A,135,27) RS1/16S123J R 302 (A,135,30) RS1/16S103J R 303 (A,137,25) RS1/16S473J R 320 (A,106,65) RS1/16S103J R 328 (A,105,67) RS1/16S101J R 329 (A,110,62) RS1/16SS821J R 330 (A,110,58) RS1/16SS221J R 331 (A,110,60) RS1/16SS221J R 332 (A,110,59) RS1/16SS472J Circuit Symbol and No. Part No. R 349 (B,156,52) RS1/16S473J R 350 (B,147,51) RS1/16S473J R 356 (A,91,74) RS1/16S0R0J R 360 (B,97,69) RS1/16SS473J R 361 (B,97,56) RS1/16SS473J R 362 (B,97,68) RS1/16SS473J R 363 (B,97,57) RS1/16SS473J R 364 (B,97,60) RS1/16SS473J R 365 (B,97,59) RS1/16SS473J R 366 (B,97,58) RS1/16SS473J R 367 (B,99,57) RS1/16SS473J R 368 (B,99,59) RS1/16SS473J R 369 (B,97,67) RS1/16SS473J R 551 (A,27,126) RS1/16S103J R 552 (A,23,126) RS1/10S103J R 553 (A,23,128) RN1/16SE1001D R 554 (A,22,130) RN1/16SE1101D R 555 (A,19,130) RN1/16SE1001D R 557 (A,39,134) RS1/10S105J R 558 (A,39,132) RS1/10S151J R 559 (B,18,72) RS1/16S104J R 560 (A,19,92) RS1/16S104J R 561 (B,20,72) RS1/16S473J R 562 (B,19,70) RS1/16S563J R 563 (B,19,74) RS1/16S513J R 564 (B,6,71) RS1/16S104J R 565 (A,25,59) RS1/16S102J R 566 (A,23,59) RS1/16S102J R 567 (A,18,106) RS1/16S0R0J R 568 (A,22,62) RS1/16S513J R 569 (A,24,63) RS1/16S513J R 570 (A,24,61) RS1/16S564J R 571 (B,7,74) RS1/16S0R0J R 572 (A,24,56) RS1/16S822J R 573 (A,23,58) RS1/16S202J R 574 (B,11,35) RS1/16S203J R 576 (B,8,35) RS1/16S333J R 577 (A,58,117) RS1/16S0R0J R 578 (A,22,93) RS1/16S0R0J R 579 (A,22,95) RS1/16S0R0J R 601 (A,107,88) RS1/16S0R0J R 602 (A,121,117) RS1/16S1803D R 603 (A,126,114) RS1/16SS1603F R 604 (A,126,117) RS1/16S1002F R 605 (A,115,96) RS1/16S101J R 606 (A,127,93) RS1/16S470J R 607 (A,107,8) RS1/16S473J R 608 (A,106,6) RS1/16S473J R 609 (A,103,5) RS1/16S473J R 610 (A,100,5) RS1/16S473J R 611 (A,95,8) RS1/16S472J R 612 (A,125,94) RS1/16S101J R 613 (A,123,94) RS1/16S101J R 614 (A,33,19) RS1/16SS0R0J R 615 (A,34,19) RS1/16SS0R0J R 616 (A,129,90) RS1/16SS101J R 617 (A,30,17) RS1/16S101J R 618 (A,33,24) RS1/16SS101J R 620 (A,50,18) RS1/16SS0R0J R 622 (A,50,15) RS1/16SS0R0J Circuit Symbol and No. Part No. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 144 1 2 3 4 1 2 3 4 C D F A B E R 623 (A,48,11) RS1/16SS0R0J R 624 (A,118,10) RS1/16S0R0J R 625 (A,32,14) RS1/16SS0R0J R 626 (A,117,7) RS1/16SS0R0J R 651 (B,151,128) RS1/16S681J R 652 (B,164,119) RS1/16S471J R 653 (B,164,118) RS1/16S471J R 654 (B,154,128) RS1/16S681J R 655 (B,149,128) RS1/16S681J R 656 (B,152,128) RS1/16S681J R 657 (B,147,128) RS1/16S681J R 701 (A,72,17) RS1/16S0R0J R 702 (A,71,17) RS1/16S0R0J R 703 (A,63,14) RS1/16S0R0J R 704 (A,61,7) RS1/16S0R0J R 705 (A,61,8) RS1/16S0R0J R 706 (A,61,10) RS1/16S0R0J R 707 (A,64,8) RS1/16S0R0J R 708 (B,72,10) RS1/16S0R0J R 709 (A,67,12) RS1/16S0R0J R 710 (A,92,103) RS1/16S101J R 711 (A,80,99) RS1/16S101J R 712 (A,83,101) RS1/16S101J R 715 (B,77,9) RS1/16S0R0J R 717 (B,83,6) RS1/16S0R0J R 751 (B,51,106) RS1/16SS101J R 752 (B,51,108) RS1/16SS101J R 753 (B,51,110) RS1/16SS101J R 754 (B,51,104) RS1/16S222J R 755 (B,50,97) RS1/16S222J R 756 (B,38,118) RS1/16S101J R 759 (B,35,110) RS1/16S242J R 760 (B,35,107) RS1/16S242J R 761 (B,35,105) RS1/16S222J R 762 (B,35,109) RS1/16S242J R 763 (B,34,114) RS1/16SS0R0J R 764 (B,32,109) RS1/16SS0R0J R 765 (B,32,105) RS1/16SS0R0J R 766 (B,30,97) RS1/16SS0R0J R 767 (B,31,96) RS1/16S222J R 768 (B,31,108) RS1/16S182J R 769 (B,31,112) RS1/16S182J R 770 (B,31,116) RS1/16S182J R 775 (A,37,109) RS1/16S0R0J R 780 (B,26,117) RS1/16S471J R 782 (B,25,110) RS1/16S471J R 783 (B,25,106) RS1/16S471J R 784 (B,26,96) RS1/16S471J R 801 (A,84,61) RS1/16S103J R 802 (A,88,66) RS1/10S360J R 803 (A,88,68) RS1/10S360J R 804 (B,68,51) RS1/16S6803D R 807 (B,44,47) RS1/8S0R0J R 808 (B,59,38) RS1/16S0R0J R 809 (B,41,46) RS1/10S102J R 810 (B,62,38) RS1/16S101J R 811 (B,62,37) RS1/16S1600D R 812 (B,65,37) RS1/16S5601D R 813 (B,67,38) RS1/16S1001D R 814 (B,66,35) RS1/16S331J Circuit Symbol and No. Part No. R 815 (B,68,30) RS1/16S1003D R 816 (B,66,30) RS1/16S6803D R 817 (B,61,54) RS1/16S0R0J R 818 (B,61,53) RS1/16S473J R 819 (B,61,56) RS1/16S3300D R 820 (B,58,56) RS1/16S1002D R 821 (B,56,56) RS1/16S5601D R 822 (B,58,57) RS1/16S331J R 823 (B,57,59) RS1/16S152J R 824 (B,57,61) RS1/16S104J R 825 (B,57,66) RS1/16S1003D R 826 (B,64,76) RS1/16S0R0J R 827 (B,62,77) RS1/16S6800D R 828 (B,59,77) RS1/16S1002D R 829 (B,56,76) RS1/16S3301D R 830 (B,59,76) RS1/16S331J R 831 (B,57,74) RS1/16S332J R 832 (B,57,71) RS1/16S104J R 851 (B,53,30) RS1/16S184J R 853 (B,62,79) RS1/16S100J R 854 (B,73,65) RS1/10S150J R 855 (B,73,69) RS1/10S150J R 859 (B,57,26) RS1/16S100J R 860 (B,51,35) RS1/10S100J R 861 (B,61,59) RS1/16S224J R 862 (B,61,73) RS1/16S224J R 867 (B,15,24) RS1/8S680J R 868 (B,18,11) RS1/8S151J R 870 (B,21,25) RS1/16S103J R 871 (B,67,25) RS1/16S473J R 873 (B,66,25) RS1/16S0R0J R 881 (B,55,77) RS1/16S274J R 890 (A,168,106) RS1/16S0R0J R 891 (B,162,106) RS1/10S472J R 892 (B,159,107) RS1/16SS223J R 893 (B,154,105) RS1/16S330J R 894 (A,137,140) RS1/8S0R0J R 895 (A,127,131) RS1/10S0R0J R 896 (A,124,131) RS1/10S0R0J R 897 (A,122,131) RS1/10S0R0J R 898 (A,120,131) RS1/10S0R0J R 900 (B,10,24) RS1/8S151J R 901 (B,13,11) RS1/8S151J R 902 (B,15,11) RS1/8S151J R 903 (A,131,124) RS1/16S0R0J CAPACITORS C 1 (B,128,27) CKSRYB104K16 C 2 (B,127,31) CKSRYB104K16 C 3 (B,127,33) CKSRYB104K16 C 4 (B,127,38) CKSRYB104K16 C 5 (B,127,50) CKSRYB104K16 C 6 (A,148,45) CKSRYB104K16 C 7 (A,152,53) CKSRYB104K16 C 8 (A,152,58) CKSRYB104K16 C 9 (A,152,61) CKSRYB104K16 C 10 (A,152,64) CKSRYB104K16 C 11 (A,152,69) CKSRYB104K16 C 12 (B,131,26) 10É F CCG1192 Circuit Symbol and No. Part No. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 145 5 6 7 8 5 6 7 8 C D F A B E C 13 (B,142,34) CKSRYB104K16 C 14 (B,142,37) CKSRYB104K16 C 15 (A,143,44) CKSRYB104K16 C 16 (A,141,44) CKSRYB104K16 C 17 (A,143,75) CKSRYB104K16 C 18 (A,141,77) CCSRCH100D50 C 19 (A,138,77) CCSRCH100D50 C 20 (B,145,27) CKSRYB104K16 C 21 (B,144,31) CKSRYB104K16 C 22 (B,144,33) CKSRYB104K16 C 23 (B,144,38) CKSRYB104K16 C 24 (B,143,49) CKSRYB104K16 C 25 (A,136,45) CKSRYB104K16 C 26 (A,137,74) CKSRYB104K16 C 27 (B,148,26) 10µF CCG1192 C 28 (B,153,24) CKSRYB104K16 C 29 (B,158,36) CKSRYB104K16 C 30 (A,154,27) CKSRYF104Z25 C 31 (B,128,67) CCSRCH9R0D50 C 32 (B,128,71) CCSRCH9R0D50 C 33 (A,132,45) CKSRYB104K16 C 35 (A,132,74) CKSRYB104K16 C 36 (A,126,74) CKSRYB104K16 C 38 (A,131,41) 10µF CCG1171 C 39 (A,123,50) CKSRYB104K16 C 40 (A,122,51) CKSRYB104K16 C 41 (A,123,59) CKSRYB104K16 C 42 (B,136,53) CKSRYB104K16 C 43 (A,48,54) CKSRYB104K16 C 44 (B,133,65) CKSRYB104K16 C 46 (A,49,73) CKSRYB104K16 C 47 (B,141,74) CKSRYB104K16 C 49 (B,139,53) CKSRYB104K16 C 51 (A,144,44) CKSRYB224K10 C 54 (B,80,42) CCSRCH121J50 C 55 (B,144,53) CKSRYB104K16 C 56 (A,39,51) CKSRYB104K16 C 57 (B,147,53) CKSRYB104K16 C 58 (A,48,51) CKSRYB104K16 C 60 (B,149,74) CKSRYB104K16 C 63 (B,154,55) CKSRYB104K16 C 64 (B,154,61) CKSRYB104K16 C 66 (B,154,63) CKSRYB104K16 C 67 (B,156,63) 10µF CCG1192 C 68 (A,126,44) 22µF CCG1178 C 69 (A,126,42) 22µF CCG1178 C 70 (A,126,38) 22µF CCG1178 C 71 (B,125,69) CKSRYF103Z50 C 72 (B,159,60) CKSRYF103Z50 C 73 (B,157,60) CKSRYF104Z25 C 74 (B,154,70) CKSRYF104Z25 C 75 (A,152,26) CKSRYF104Z25 C 76 (B,127,36) CKSRYF103Z50 C 77 (B,135,26) CKSRYF103Z50 C 78 (B,142,30) CKSRYF103Z50 C 79 (B,158,38) CKSRYB103K50 C 80 (B,151,26) CKSRYB103K50 C 81 (B,143,48) CKSRYB224K10 C 82 (B,158,31) CKSRYB103K50 C 96 (B,160,31) CKSRYB224K10 Circuit Symbol and No. Part No. C 97 (B,160,36) CKSRYB224K10 C 98 (B,160,38) CKSRYB224K10 C 101 (A,128,27) CKSRYB104K16 C 102 (A,131,20) CKSRYB104K16 C 103 (A,135,34) CKSRYB104K16 C 104 (A,144,38) CKSRYB104K16 C 105 (A,152,38) CKSRYB104K16 C 106 (A,160,38) CKSRYB104K16 C 107 (A,156,42) CKSRYB104K16 C 108 (A,156,50) CKSRYB104K16 C 109 (A,156,59) CKSRYB104K16 C 110 (B,102,51) 10µF CCG1171 C 111 (B,102,48) CKSRYB104K16 C 112 (B,102,43) CKSRYF224Z16 C 113 (B,102,36) 10µF CCG1171 C 114 (B,102,33) CKSRYB104K16 C 115 (B,102,28) CKSRYF224Z16 C 116 (B,115,73) CKSRYF104Z25 C 117 (B,103,60) 10µF CCG1171 C 118 (B,103,59) CKSRYB104K16 C 119 (B,115,58) CKSRYF104Z25 C 120 (B,105,71) CKSRYF104Z25 C 121 (B,105,66) CKSRYF104Z25 C 122 (B,100,47) CKSRYF104Z25 C 123 (B,102,63) CKSRYF103Z50 C 124 (B,126,49) CCSRCH101J50 C 125 (A,162,42) CKSRYF104Z25 C 126 (A,162,59) CKSRYF104Z25 C 201 (A,120,46) CKSRYB104K16 C 202 (A,115,51) CKSRYB104K16 C 203 (A,113,51) CKSRYB104K16 C 204 (A,118,46) CKSRYB104K16 C 205 (A,107,51) CKSRYB104K16 C 206 (A,102,50) CKSRYB104K16 C 207 (A,96,51) CKSRYB104K16 C 208 (A,92,51) CKSRYB104K16 C 209 (A,83,46) CKSRYB104K16 C 211 (A,118,43) CKSRYB104K16 C 213 (A,118,41) CKSRYB104K16 C 214 (A,119,41) CKSRYB104K16 C 215 (A,83,44) CKSRYB104K16 C 216 (A,83,41) CKSRYB104K16 C 217 (A,83,39) CKSRYB104K16 C 220 (A,121,41) 10µF CCG1171 C 221 (A,118,38) CKSRYB104K16 C 222 (A,118,35) CKSRYB104K16 C 223 (A,120,17) CKSRYB224K10 C 224 (A,118,33) CKSRYB104K16 C 225 (A,119,38) CKSRYB104K16 C 227 (A,83,38) CKSRYB104K16 C 228 (A,83,33) CKSRYB104K16 C 230 (A,123,34) CCSRCH150J50 C 231 (A,123,25) CCSRCH120J50 C 232 (A,118,30) CKSRYB104K16 C 233 (A,118,27) CKSRYB104K16 C 234 (A,83,29) CKSRYB104K16 C 235 (A,84,27) CKSRYB104K16 C 237 (A,118,24) CKSRYB104K16 C 238 (A,119,22) CKSRYB104K16 C 239 (A,84,26) CKSRYB104K16 Circuit Symbol and No. Part No. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 146 1 2 3 4 1 2 3 4 C D F A B E C 240 (A,84,23) CKSRYB104K16 C 241 (A,84,21) CKSRYB104K16 C 242 (A,112,17) CKSRYB104K16 C 243 (A,108,17) CKSRYB104K16 C 244 (A,105,17) CKSRYB104K16 C 245 (A,102,17) CKSRYB104K16 C 246 (A,98,17) CKSRYB104K16 C 247 (A,94,17) CKSRYB104K16 C 248 (A,89,17) CKSRYB104K16 C 249 (A,84,17) 10µF CCG1171 C 250 (A,104,52) 10µF CCG1171 C 251 (A,120,34) 10µF CCG1171 C 252 (A,85,51) 10µF CCG1171 C 253 (A,121,23) CKSRYF104Z25 C 255 (A,83,42) CKSRYB103K50 C 256 (A,83,36) CKSRYB103K50 C 257 (A,83,35) CKSRYB103K50 C 258 (A,83,31) CKSRYB103K50 C 259 (A,83,30) CKSRYB103K50 C 260 (A,84,24) CKSRYB103K50 C 261 (A,80,17) CKSRYB103K50 C 262 (A,79,17) CKSRYB103K50 C 301 (A,137,30) CKSRYF104Z25 C 302 (A,144,30) CKSRYB334K10 C 303 (A,138,21) CKSRYF104Z25 C 306 (A,116,57) CKSRYF104Z25 C 323 (A,103,65) 10µF CCG1171 C 328 (A,100,59) CKSRYB104K16 C 329 (A,98,59) 10µF CCG1171 C 341 (A,156,27) CCSRCH101J50 C 342 (A,136,23) CKSRYF104Z25 C 344 (B,142,20) CKSRYF103Z50 C 345 (B,140,20) CKSRYF104Z25 C 346 (B,126,20) CKSRYF103Z50 C 347 (B,115,19) CKSRYF103Z50 C 348 (B,114,17) CKSRYF104Z25 C 349 (B,92,16) CKSRYF103Z50 C 356 (A,109,64) CKSRYB102K50 C 357 (A,93,75) CKSRYB102K50 C 370 (A,89,79) CKSRYB102K50 C 552 (A,29,129) CKSRYB104K16 C 553 (A,41,137) CKSRYB105K10 C 554 (A,38,136) CKSRYB103K50 C 555 (A,35,134) CKSYB106K6R3 C 556 (B,9,76) CKSRYF104Z25 C 557 (B,8,71) CKSRYB102K50 C 559 (A,18,97) CKSRYF104Z25 C 560 (A,20,100) CKSRYF104Z25 C 561 (A,18,103) CKSRYF104Z25 C 562 (A,19,53) CKSRYB104K16 C 563 (A,20,51) CKSRYB104K25 C 564 (B,17,35) CKSRYB103K50 C 566 (B,15,35) CKSRYB823K16 C 567 (B,22,128) CCSRCH102J50 C 568 (B,26,128) CKSRYB104K16 C 602 (A,118,115) CKSSYF104Z16 C 603 (A,120,115) CKSSYF104Z16 C 604 (A,119,117) CKSSYB104K10 C 605 (A,127,95) CCSRCH101J50 C 606 (A,112,96) CCSRCH471J50 Circuit Symbol and No. Part No. C 607 (A,114,93) CCSRCH101J50 C 608 (A,97,8) CKSRYB103K50 C 609 (A,111,7) CKSRYF104Z25 C 610 (A,131,94) CCSRCH101J50 C 611 (A,130,91) CCSRCH471J50 C 651 (A,148,120) CKSQYB475K6R3 C 652 (A,149,118) CKSSYB103K16 C 653 (A,149,116) CKSRYB105K10 C 654 (A,152,115) CKSRYB105K10 C 655 (A,155,115) CKSRYB105K10 C 656 (A,153,129) CKSSYB102K50 C 657 (A,150,123) CKSRYB105K10 C 658 (A,148,123) CKSRYB105K10 C 659 (A,152,129) CKSSYB102K50 C 665 (B,163,127) CKSRYB104K16 C 666 (A,148,126) CKSQYF104Z50 C 667 (A,147,129) CKSQYF104Z50 C 701 (B,83,10) CKSRYF104Z25 C 702 (B,82,9) CKSRYF104Z25 C 705 (A,70,12) CKSRYF104Z50 C 707 (A,89,103) CKSRYF104Z25 C 751 (A,47,104) CKSRYB104K16 C 752 (B,48,110) CKSRYB104K16 C 753 (B,48,108) CKSRYB104K16 C 754 (B,48,106) CKSRYB104K16 C 755 (B,48,99) CCSRCH470J50 C 756 (B,48,104) CCSRCH5R0C50 C 758 (A,45,97) CEVQW470M16 C 759 (B,49,96) CKSRYB105K6R3 C 760 (B,44,115) CKSQYB225K10 C 761 (B,42,116) CKSSYB103K16 C 762 (B,35,100) CCSRCH220J50 C 766 (B,35,103) CKSRYB105K6R3 C 767 (A,38,104) CEVQW470M16 C 772 (A,45,110) CKSRYB104K16 C 774 (B,32,118) CKSQYB475K6R3 C 775 (B,31,106) CCSRCH220J50 C 776 (B,31,110) CCSRCH220J50 C 777 (B,31,115) CCSRCH220J50 C 801 (A,135,88) CKSRYF104Z25 C 802 (A,134,88) CKSRYB103K50 C 803 (B,108,89) CKSRYF104Z25 C 804 (B,107,87) CKSRYB103K50 C 805 (A,91,66) CKSRYB103K50 C 806 (A,96,69) CEVW101M16 C 807 (B,93,90) CKSRYB103K50 C 808 (A,90,90) CEVW220M6R3 C 809 (B,97,99) 10µF CCG1171 C 810 (B,76,91) CKSRYF104Z25 C 811 (A,97,91) CEVW101M6R3 C 812 (B,103,87) CKSRYF104Z25 C 813 (A,66,91) CKSRYB103K50 C 814 (B,76,88) CKSRYB103K50 C 815 (A,61,90) CKSRYF104Z25 C 816 (A,63,90) CKSRYB103K50 C 817 (B,103,95) CKSRYF104Z25 C 818 (B,65,38) CKSRYB473K50 C 819 (B,66,33) CCSRCH101J50 C 820 (B,69,34) CKSRYB224K16 C 821 (B,65,40) CKSRYB103K50 Circuit Symbol and No. Part No. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 147 5 6 7 8 5 6 7 8 C D F A B E C 822 (B,68,32) 15pF CCG1215 C 823 (B,64,26) CKSRYB105K10 C 824 (B,61,57) CKSRYB822K50 C 825 (B,59,59) CKSRYB152K50 C 826 (B,57,60) CKSRYB563K16 C 827 (B,57,63) CKSRYB103K50 C 828 (B,57,64) 15pF CCG1215 C 829 (B,62,76) CKSRYB822K50 C 830 (B,59,73) CKSRYB152K50 C 831 (B,57,73) CKSRYB563K16 C 832 (B,57,67) CKSRYB105K10 C 833 (B,57,70) CKSRYB103K50 C 834 (B,92,88) 10µF CCG1171 C 835 (A,86,79) CKSRYB104K16 C 836 (A,139,89) CKSRYB104K16 C 837 (A,89,56) CKSRYB104K16 C 844 (B,53,32) CKSRYF104Z25 C 845 (B,53,26) CKSYB475K10 C 846 (B,53,34) CKSRYF474Z16 C 847 (B,65,80) 4.7µF CCG1111 C 848 (B,64,60) CKSRYF474Z16 C 849 (B,65,72) CKSRYF474Z16 C 853 (A,56,35) 220µF/10V CCH1409 C 854 (B,61,25) 4.7µF CCG1111 C 855 (B,61,60) CKSRYF104Z25 C 856 (A,60,64) 10µF CCG1173 C 857 (B,65,52) CKSYB475K10 C 858 (B,61,74) CKSRYF104Z25 C 859 (A,63,64) 10µF CCG1173 C 860 (A,63,59) 4.7µF CCG1111 C 867 (B,45,26) 4.7µF CCG1111 C 868 (B,49,25) 4.7µF CCG1111 C 869 (A,57,27) 10µF CCG1173 C 870 (A,54,27) 10µF CCG1173 C 871 (B,45,29) 4.7µF CCG1111 C 872 (A,60,59) 4.7µF CCG1111 C 873 (A,80,62) 330µF/6.3V CCH1366 C 874 (B,68,76) 4.7µF CCG1111 C 875 (A,56,63) 10µF CCG1173 C 876 (A,56,60) 10µF CCG1173 C 877 (A,64,80) CKSRYB104K25 C 878 (A,81,73) 330µF/6.3V CCH1366 C 879 (B,68,58) 4.7µF CCG1111 C 881 (A,11,62) CEAT472M16(P35) C 882 (A,11,44) CEAT472M16(P35) C 890 (A,166,100) CEVW101M16 C 891 (A,150,94) CEVW101M16 C 892 (B,159,94) CKSRYF104Z25 C 893 (A,158,94) CEVW101M16 C 894 (B,24,11) CKSRYF104Z25 C 895 (A,13,18) CEAT221M25(P35) C 896 (B,21,27) CKSRYF104Z25 C 897 (A,13,29) 2200µF/16V CCH1659(P35) C 898 (A,150,107) CEVW101M16 C 899 (A,158,107) CEVW101M16 B Unit Number:CWX3141 Unit Name:GPS Unit Circuit Symbol and No. Part No. MISCELLANEOUS IC 401 (A,25,17) IC UPC2749T IC 402 (B,20,28) IC UPB1027GS IC 441 (A,32,30) IC NJM2100V IC 461 (B,29,10) IC ADC12H034CIMSAS1 IC 501 (B,50,26) IC PD3390A IC 502 (B,48,9) IC PD6519A IC 503 (A,49,29) IC M5M5V216ATP-70HI IC 504 (A,31,14) IC MAX6364PUT29 Q 441 (A,32,22) Transistor 2SB1132 D 401 (B,11,28) Diode 1SV314 D 501 (B,35,30) Diode RB751V40 L 401 (B,11,29) Inductor CTF1549 L 402 (B,26,22) Inductor CTF1486 L 403 (B,27,26) Inductor CTF1486 L 404 (A,21,23) Inductor LCSA3N3R1608 L 405 (B,13,24) Inductor LCYB22NJ1608 L 406 (B,15,20) Inductor LCYB22NJ1608 L 407 (A,19,32) Inductor CTF1410 L 408 (B,26,32) Inductor CTF1556 L 409 (B,18,12) Inductor LCYC1R0K2125 L 410 (B,26,17) Inductor CTF1547 L 412 (A,25,27) Inductor CTF1547 L 413 (A,25,26) Inductor CTF1547 L 414 (A,25,32) Inductor CTF1547 L 415 (A,26,29) Inductor CTF1547 L 416 (A,26,28) Inductor CTF1547 L 417 (B,25,20) Inductor CTF1547 L 418 (A,14,33) Inductor CTF1410 L 441 (B,32,20) Inductor CTF1410 L 442 (A,29,25) Inductor CTF1410 L 461 (A,28,9) Inductor CTF1410 L 462 (A,31,8) Inductor CTF1410 L 467 (B,33,17) Inductor CTF1547 L 468 (B,32,17) Inductor CTF1547 L 469 (A,32,11) Inductor CTF1410 L 501 (B,38,17) Inductor CTF1410 L 502 (B,36,32) Inductor CTF1410 L 503 (B,59,6) Inductor CTF1410 L 504 (A,38,33) Inductor CTF1410 L 531 (A,53,18) Inductor CTF1410 X 401 (A,14,27) TCXO 16.368MHz CWX2381 X 501 (A,37,26) Radiator 32.768kHz CSS1319 X 502 (B,36,26) Radiator 20.00MHz CSS1549 F 401 (A,23,23) Filter CTF1548 RESISTORS R 401 (B,11,26) RS1/16SS472J R 402 (B,12,30) RS1/16SS472J R 403 (B,14,32) RS1/16SS122J R 404 (B,14,30) RS1/16SS622J R 405 (A,23,26) RS1/16SS100J R 406 (B,27,29) RS1/16S271J R 407 (B,25,18) RS1/16S2R2J R 441 (A,30,27) RN1/16SC10R0D R 442 (B,32,24) RN1/16SE1501D R 443 (B,31,24) RN1/16SE2402D R 444 (B,31,27) RN1/16SE3302D Circuit Symbol and No. Part No. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 148 1 2 3 4 1 2 3 4 C D F A B E R 445 (B,31,33) RN1/16SE4702D R 446 (B,30,33) RN1/16SE4702D R 447 (A,33,25) RS1/16S432J R 448 (B,32,30) RN1/16SE1002D R 449 (B,33,32) RN1/16SE2202D R 450 (B,31,32) RN1/16SE3302D R 451 (A,29,32) RS1/16S103J R 452 (B,33,27) RS1/16SS102J R 454 (B,33,26) RS1/16SS102J R 460 (B,22,13) RS1/16S0R0J R 461 (A,37,5) RS1/16SS102J R 462 (A,38,9) RS1/16SS102J R 463 (B,35,12) RAB4CQ102J R 464 (A,35,12) RAB4CQ333J R 465 (A,39,8) RS1/16SS102J R 470 (B,35,7) RAB4CQ471J R 471 (B,35,4) RAB4CQ104J R 477 (B,31,17) RS1/16SS222J R 478 (B,30,16) RS1/16SS222J R 479 (B,28,16) RS1/16SS222J R 480 (B,28,17) RS1/16SS332J R 481 (B,30,17) RS1/16SS332J R 482 (A,38,6) RS1/16SS223J R 483 (A,38,5) RS1/16SS473J R 501 (B,39,27) RS1/16SS0R0J R 502 (B,38,29) RS1/16SS102J R 503 (B,38,26) RS1/16SS154J R 508 (B,60,14) RS1/16SS103J R 509 (B,34,15) RS1/16SS473J R 510 (A,38,7) RS1/16SS102J R 511 (A,34,19) RS1/16SS103J R 512 (B,39,31) RS1/16SS473J R 513 (B,60,16) RS1/16SS103J R 514 (B,39,29) RS1/16SS473J R 515 (A,30,12) RS1/16SS473J R 517 (B,39,23) RS1/16SS103J R 519 (B,39,21) RS1/16SS473J R 521 (B,37,29) RS1/16SS473J R 533 (A,40,19) RS1/16SS103J R 534 (A,41,19) RS1/16SS103J R 535 (A,38,13) RS1/16SS103J R 536 (A,39,19) RS1/16SS0R0J CAPACITORS C 401 (A,25,13) CCSRCH100D50 C 402 (A,24,20) CCSSCH101J50 C 403 (A,27,16) CKSSYB104K10 C 404 (A,20,24) CCSSCH101J50 C 405 (B,14,28) CCSRUJ220J50 C 406 (B,14,29) CCSRUJ220J50 C 407 (B,13,32) CKSSYB333K16 C 408 (B,12,32) CKSSYB182K50 C 409 (A,21,29) CSZS100M6R3 C 410 (B,27,32) CKSSYB103K16 C 411 (A,21,27) CKSSYB102K50 C 412 (A,21,28) CKSSYB102K50 C 413 (A,20,31) CKSSYB104K10 C 414 (A,23,32) CKSSYB104K10 C 415 (A,24,30) CKSSYB104K10 Circuit Symbol and No. Part No. C 416 (A,24,28) CKSSYB104K10 C 417 (B,24,22) CKSSYB104K10 C 418 (A,21,32) CKSSYB102K50 C 419 (B,39,32) CKSSYB104K10 C 420 (A,14,32) CKSSYB104K10 C 421 (B,26,27) CKSSYB102K50 C 422 (B,25,26) CKSSYB103K16 C 423 (B,26,24) CKSSYB104K10 C 424 (B,27,22) CCSRCH102J50 C 425 (B,29,24) CCSRCH271J50 C 426 (B,28,26) CCSRCH102J50 C 427 (B,25,25) CKSSYB104K10 C 428 (B,14,24) CKSSYB103K16 C 429 (B,12,24) CCSRCH301J50 C 430 (B,12,22) CCSSCH120J50 C 431 (B,14,20) CCSRCH301J50 C 432 (B,16,22) CKSSYB103K16 C 433 (B,19,10) CCSRCH101J50 C 434 (B,18,14) CKSSYB102K50 C 435 (B,19,14) CKSSYB103K16 C 436 (B,31,22) CKSSYB104K10 C 441 (B,31,28) CKSRYB104K16 C 442 (A,30,29) CCSRCH101J50 C 443 (A,30,32) CKSRYB104K16 C 444 (B,32,22) CKSSYB103K16 C 445 (A,29,30) CKSSYB104K10 C 461 (A,28,5) 22µF/6.3V CCH1408 C 462 (A,31,10) CKSRYB104K16 C 463 (A,27,9) CKSRYB104K16 C 464 (B,31,5) CKSSYB103K16 C 465 (B,31,4) CKSSYB103K16 C 466 (B,32,4) CKSSYB103K16 C 467 (B,33,4) CKSSYB103K16 C 468 (A,30,11) CKSSYB104K10 C 469 (B,27,4) CSZS100M10 C 470 (B,26,16) CKSSYB104K10 C 471 (B,37,6) CCSSCH101J50 C 501 (B,39,19) CKSSYB104K10 C 502 (B,36,22) CCSRCH150J50 C 503 (B,38,22) CCSRCH150J50 C 504 (B,40,17) CKSSYB104K10 C 506 (B,60,19) CKSSYB104K10 C 507 (B,60,21) CKSSYB104K10 C 508 (B,60,26) CKSSYB104K10 C 509 (B,60,30) CKSSYB104K10 C 511 (B,40,34) CKSSYB104K10 C 512 (B,38,31) CKSSYB104K10 C 514 (A,31,17) CSZS100M6R3 C 515 (B,39,24) CKSSYB104K10 C 516 (B,59,11) CKSSYB104K10 C 517 (A,51,21) CKSSYB104K10 C 518 (A,39,32) CKSSYB104K10 G Unit Number:CWM9918 Unit Name:System Unit MISCELLANEOUS IC 1001 (B,13,55) IC NJM2137V Circuit Symbol and No. Part No. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 149 5 6 7 8 5 6 7 8 C D F A B E IC 1002 (A,25,70) IC NJM2137V IC 1003 (B,13,67) IC NJM2137V IC 1201 (B,23,62) IC NJM2235V IC 1202 (A,16,50) IC NJM2235V IC 1204 (A,17,63) IC NJM2561F1 IC 1501 (B,86,18) IC TC74VHCT08AFTS1 IC 1502 (A,84,31) IC PE5478A IC 1503 (A,63,42) IC TC7SH08FUS1 IC 1505 (A,93,57) IC TC7S04FU IC 1506 (B,102,49) IC S-80840CNMC-B8Z IC 1507 (A,96,57) IC TC7SH00FUS1 IC 1601 (B,56,22) IC HA12240FP IC 1801 (B,44,76) IC TPD1018F IC 1840 (A,127,67) IC S-812C50AUA-C3E IC 1900 (A,135,82) IC M5237ML IC 1902 (B,128,78) IC S-812C50AUA-C3E IC 4001 (A,40,46) IC PML009A IC 4100 (B,43,67) IC NJM2058V IC 4200 (A,80,116) IC PAL007B IC 4301 (A,147,45) IC NJM2391DL1-33 IC 4401 (B,43,38) IC TA2050FS1 IC 4500 (B,48,54) IC NJM2068V Q 1201 (B,23,46) Transistor 2SC4081 Q 1501 (A,61,21) Transistor IMD2A Q 1502 (B,94,32) Transistor 2SC4081 Q 1503 (B,95,48) Transistor UMD2N Q 1601 (B,92,44) Transistor 2SA1576 Q 1602 (B,95,40) Transistor DTC124EU Q 1802 (A,64,37) Transistor 2SA1576 Q 1810 (A,62,31) Transistor DTC114EU Q 1820 (A,60,38) Transistor DTC114EU Q 1821 (A,63,27) Transistor 2SA1576 Q 1841 (A,137,65) Transistor 2SB1184F5 Q 1842 (B,89,82) Transistor 2SD1767 Q 1850 (B,131,69) Transistor UMD2N Q 1851 (B,120,68) Transistor 2SD1760F5 Q 1860 (B,81,78) Transistor IMX1 Q 1861 (B,93,15) Transistor 2SC4081 Q 1881 (B,129,97) Transistor DTC114EU Q 1882 (B,129,91) Transistor 2SA1587 Q 1883 (B,135,94) Transistor IMX1 Q 1884 (B,142,83) Transistor 2SD1760F5 Q 1885 (B,135,100) Transistor DTC114EU Q 1900 (A,121,87) Transistor 2SB1185 Q 1901 (A,118,83) Transistor UMX1N Q 1902 (A,134,87) Transistor 2SB1185 Q 1903 (A,142,71) Transistor 2SB1260 Q 1904 (A,139,76) Transistor DTC114EU Q 1920 (B,141,24) Transistor 2SB1260 Q 1922 (A,162,8) Transistor 2SD2396 Q 1923 (A,160,10) Transistor UMF23N Q 1924 (B,133,25) Transistor DTC114EU Q 1940 (B,135,55) Transistor DTC144EU Q 1941 (B,139,58) Transistor 2SA1577 Q 1942 (B,145,55) Transistor 2SD1760F5 Q 1943 (B,148,47) Transistor UMD2N Q 1960 (A,59,42) Transistor 2SA1576 Q 4201 (A,85,90) Transistor 2SC4081 Q 4202 (A,78,94) Transistor UMD2N Q 4203 (B,17,93) Transistor DTC323TU Circuit Symbol and No. Part No. Q 4204 (B,10,90) Transistor DTC323TU Q 4205 (B,11,95) Transistor DTC323TU Q 4206 (B,14,84) Transistor DTC323TU Q 4207 (B,15,88) Transistor DTC323TU Q 4208 (B,10,84) Transistor DTC323TU Q 4209 (A,88,98) Transistor DTC124EU Q 4210 (A,83,97) Transistor UMD2N Q 4211 (A,81,89) Transistor UMD2N Q 4212 (A,92,100) Transistor DTC124EU Q 4500 (B,39,60) Transistor UMD2N Q 4501 (B,50,61) Transistor DTC323TU Q 4502 (B,44,61) Transistor DTC323TU Q 4503 (B,54,61) Transistor UMD2N D 1401 (A,22,109) Diode UMZ6R8N D 1402 (A,22,105) Diode UMZ6R8N D 1403 (A,26,109) Diode UMZ6R8N D 1404 (A,14,109) Diode UMZ6R8N D 1405 (A,29,109) Diode UMZ6R8N D 1406 (A,16,104) Diode UMZ6R8N D 1407 (A,26,105) Diode UMZ6R8N D 1408 (A,18,109) Diode UMZ6R8N D 1409 (A,20,103) Diode UMZ6R8N D 1450 (B,102,108) Diode UDZS5R6(B) D 1451 (B,102,102) Diode UDZS5R6(B) D 1501 (B,95,52) Diode 1SS355 D 1651 (A,53,16) Diode UDZS5R6(B) D 1652 (A,50,16) Diode UDZS5R6(B) D 1801 (A,47,86) Diode S1G-6904G2P D 1802 (A,46,99) Diode 1SS355 D 1803 (A,45,95) Diode 1SS355 D 1804 (A,47,89) Diode PZT27(B) D 1805 (A,61,100) Diode S1G-6904G2P D 1806 (B,55,116) Diode PZT27(B) D 1810 (A,59,32) Diode 1SS355 D 1811 (A,59,30) Diode RB500V-40 D 1812 (A,51,93) Diode UDZS18(B) D 1813 (A,49,92) Diode UDZS18(B) D 1814 (A,59,29) Diode UDZS6R8(B) D 1815 (A,54,100) Diode S1G-6904G2P D 1820 (A,45,99) Diode 1SS400 D 1821 (A,45,92) Diode DAN202U D 1822 (A,28,98) Diode 5KP22A D 1841 (B,95,80) Diode UDZS20(B) D 1850 (B,127,71) Diode HZU6R2(B1) D 1860 (B,71,87) Diode HZU7R5(B3) D 1861 (B,79,84) Diode KS926S2 D 1862 (B,88,78) Diode RB500V-40 D 1863 (B,88,76) Diode UDZS18(B) D 1864 (B,77,79) Diode RB500V-40 D 1865 (B,96,16) Diode HZU6R8(B2) D 1866 (A,106,89) Diode S1G-6904G2P D 1867 (A,107,85) Diode RB500V-40 D 1880 (B,137,92) Diode RB500V-40 D 1881 (B,139,92) Diode RB500V-40 D 1882 (B,136,102) Diode HZU9R1(B1) D 1883 (B,141,91) Diode HZU13(B1) D 1900 (A,124,82) Diode HZU8R2(B1) D 1901 (A,122,79) Diode 1SS355 D 1921 (A,155,9) Diode HZU8R2(B2) D 1940 (B,146,47) Diode HZU11(B2) Circuit Symbol and No. Part No. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 150 1 2 3 4 1 2 3 4 C D F A B E D 1960 (A,40,91) Diode 1SS355 D 1961 (A,37,102) Diode 1SS355 D 4200 (A,89,94) Diode DAN202U D 4201 (A,88,90) Diode DAN202U D 4202 (A,79,91) Diode UDZS8R2(B) D 4203 (A,76,91) Diode MA111 D 4204 (A,91,97) Diode DAN202U D 4300 (A,148,54) Diode 1SR154-400 D 4301 (A,148,51) Diode 1SR154-400 D 4302 (A,148,58) Diode 1SR154-400 D 4500 (B,57,57) Diode DAN202U D 4501 (B,60,57) Diode DAN202U D 4502 (B,56,53) Diode DAN202U D 4600 (A,59,61) Diode 1SS355 D 4601 (A,57,54) Diode UDZS4R7(B) ZNR4300 (B,157,91) Surge Protector CSA30-201N L 1001 (A,16,53) Inductor CTF1399 L 1002 (A,31,69) Inductor CTF1399 L 1003 (A,11,56) Inductor CTF1399 L 1201 (A,38,67) Inductor CTF1334 L 1202 (B,28,67) Inductor LCYC2R2K1608 L 1203 (A,22,45) Inductor LCYC2R2K1608 L 1204 (A,25,50) Inductor CTF1334 L 1205 (A,24,64) Inductor LCYC2R2K1608 L 1207 (B,25,34) Inductor LCYC2R2K1608 L 1301 (B,106,48) Inductor CTF1389 L 1302 (B,107,55) Inductor CTF1389 L 1303 (B,119,49) Inductor CTF1389 L 1304 (B,119,55) Inductor CTF1389 L 1305 (B,111,47) Inductor LCTAW2R2J2520 L 1401 (A,16,101) Inductor CTF1334 L 1402 (A,15,101) Inductor CTF1334 L 1403 (A,13,102) Inductor CTF1334 L 1404 (A,18,101) Inductor CTF1334 L 1405 (A,12,109) Inductor CTF1306 L 1406 (A,11,105) Inductor CTF1306 L 1407 (A,10,109) Inductor CTF1306 L 1408 (A,9,105) Inductor CTF1306 L 1409 (A,8,109) Inductor CTF1306 L 1410 (A,7,105) Inductor CTF1306 L 1450 (B,104,112) Inductor CTF1334 L 1451 (B,104,106) Inductor CTF1334 L 1501 (A,97,43) Inductor CTF1379 L 1502 (B,90,20) Inductor CTF1334 L 1503 (A,70,23) Inductor CTF1379 L 1504 (A,98,22) Inductor CTF1379 L 1505 (A,70,39) Inductor CTF1379 L 1506 (A,62,44) Inductor CTF1334 L 1507 (A,83,49) Inductor CTF1379 L 1508 (A,94,61) Inductor CTF1334 L 1509 (A,95,61) Inductor CTF1334 L 1510 (B,99,51) Inductor CTF1334 L 1605 (B,52,23) Inductor LCTAW2R2J2520 L 1651 (A,50,22) Inductor CTF1306 L 1652 (A,49,22) Inductor CTF1306 L 1701 (B,24,19) Inductor CTF1463 L 1702 (B,23,23) Inductor CTF1463 L 1703 (B,31,18) Ferrite Bead CTF1528 L 1704 (A,42,6) Ferrite Bead CTF1528 L 1705 (A,40,7) Ferrite Bead CTF1528 Circuit Symbol and No. Part No. L 1801 (A,46,102) Inductor CTF1556 L 1802 (A,50,102) Inductor CTF1556 L 1810 (A,32,91) Inductor CTF1306 L 1811 (A,52,103) Inductor CTF1306 L 1822 (A,42,92) Inductor LCTC2R2K1608 L 1823 (A,45,102) Inductor CTF1556 L 1830 (A,81,85) Choke Coil 100µH CTH1315 L 1960 (A,36,94) Inductor CTF1556 L 4000 (A,26,39) Inductor LCTAW2R2J2520 L 4300 (B,155,54) Inductor LCTAW1R0J2520 L 4301 (B,157,86) Inductor LCTAW4R7J2520 L 4302 (B,155,32) Inductor LCTAW1R0J2520 L 4303 (B,156,75) Inductor LCTAW1R0J2520 X 1501 (A,86,46) Radiator 12.58MHz CSS1601 >FU1401 (A,28,90) Fuse 3.15A CEK1259 >FU1402 (A,11,97) Fuse 3A CEK1286 >FU1820 (B,47,84) Fuse 2A CEK1257 >FU1821 (B,41,81) Fuse 2A CEK1257 >FU1823 (A,101,89) Fuse 4A CEK1288 >FU1830 (A,78,80) Fuse 1A CEK1254 >FU1840 (A,122,67) Fuse 250mA CEK1276 >FU1880 (A,101,95) Fuse 0.5A CEK1278 >FU1900 (A,143,74) Fuse 1A CEK1280 >FU1920 (A,144,33) Fuse 1.75A CEK1283 EF1401 (A,29,105) EMI Filter CCG1067 EF1402 (A,14,79) EMI Filter CCG1067 EF1403 (A,22,91) EMI Filter CCG1067 EF1801 (A,41,100) EMI Filter CCG1172 EF1820 (B,42,88) EMI Filter CCG1172 EF1821 (B,38,89) EMI Filter CCG1172 RESISTORS R 1001 (B,12,41) RS1/16SS750J R 1002 (B,11,43) RS1/16SS103J R 1003 (A,24,90) RS1/16SS750J R 1004 (A,24,80) RS1/16SS103J R 1005 (B,14,80) RS1/16SS750J R 1006 (B,13,78) RS1/16SS103J R 1007 (B,14,43) RS1/16SS103J R 1008 (A,26,80) RS1/16SS103J R 1009 (B,11,78) RS1/16SS103J R 1010 (B,13,47) RS1/16S4701D R 1011 (B,11,49) RS1/16S4701D R 1012 (A,28,79) RS1/16S4701D R 1013 (A,23,77) RS1/16S4701D R 1014 (B,12,74) RS1/16S4701D R 1015 (B,14,73) RS1/16S4701D R 1016 (B,16,51) RS1/16SS101J R 1017 (B,14,49) RS1/16S4701D R 1018 (B,11,50) RS1/16S4701D R 1019 (B,10,52) RS1/16SS102J R 1020 (A,29,75) RS1/16SS101J R 1021 (A,26,76) RS1/16S4701D R 1022 (A,23,75) RS1/16S4701D R 1023 (A,22,68) RS1/16SS102J R 1024 (B,10,70) RS1/16SS101J R 1025 (B,11,73) RS1/16S4701D R 1026 (B,14,72) RS1/16S4701D R 1027 (B,15,70) RS1/16SS102J Circuit Symbol and No. Part No. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 151 5 6 7 8 5 6 7 8 C D F A B E R 1028 (B,13,60) RS1/16SS563J R 1029 (B,17,56) RS1/16SS473J R 1030 (A,28,69) RS1/16SS563J R 1031 (A,29,71) RS1/16SS473J R 1032 (B,12,62) RS1/16SS563J R 1033 (B,10,66) RS1/16SS473J R 1201 (B,23,65) RS1/16SS105J R 1202 (A,14,46) RS1/16SS105J R 1203 (B,23,66) RS1/16SS105J R 1204 (A,14,47) RS1/16SS105J R 1205 (B,23,69) RS1/16SS105J R 1207 (A,17,60) RS1/16SS105J R 1208 (B,17,50) RS1/16SS0R0J R 1213 (A,19,76) RS1/16SS750J R 1217 (B,21,48) RS1/16S0R0J R 1218 (B,24,42) RS1/16S183J R 1219 (A,24,43) RS1/16SS0R0J R 1220 (B,22,44) RS1/16SS102J R 1301 (B,109,54) RS1/16SS101J R 1302 (B,113,48) RS1/16SS101J R 1303 (B,113,54) RS1/16SS101J R 1304 (B,122,55) RS1/16SS101J R 1305 (B,123,48) RS1/16SS101J R 1501 (B,91,17) RS1/16SS104J R 1502 (B,89,17) RS1/16SS104J R 1503 (B,82,18) RS1/16SS104J R 1504 (B,82,20) RS1/16SS104J R 1505 (A,65,17) RS1/16SS103J R 1506 (A,65,18) RS1/16SS103J R 1507 (B,78,9) RS1/16SS473J R 1508 (A,79,14) RS1/16SS473J R 1509 (A,80,14) RS1/16SS473J R 1510 (A,81,14) RS1/16SS473J R 1511 (B,81,13) RS1/16SS473J R 1512 (B,82,12) RS1/16SS473J R 1513 (B,84,12) RS1/16SS104J R 1514 (B,86,11) RS1/16SS104J R 1515 (A,65,16) RS1/16SS102J R 1516 (A,65,19) RS1/16SS102J R 1518 (B,78,13) RS1/16SS473J R 1519 (B,94,22) RS1/16SS0R0J R 1520 (B,94,21) RS1/16SS0R0J R 1521 (A,77,14) RAB4C681J R 1522 (A,84,14) RAB4C681J R 1523 (A,88,14) RAB4C681J R 1524 (A,92,14) RAB4C681J R 1525 (A,70,19) RAB4C681J R 1526 (A,96,15) RS1/16SS681J R 1527 (B,101,15) RS1/16SS104J R 1529 (A,98,19) RAB4C681J R 1530 (B,101,14) RS1/16SS104J R 1531 (A,70,25) RAB4C681J R 1532 (A,98,25) RAB4C681J R 1533 (A,70,28) RS1/16SS681J R 1534 (B,99,25) RS1/16SS473J R 1535 (A,70,30) RAB4C681J R 1536 (B,97,27) RS1/16SS473J R 1537 (A,97,27) RS1/16SS681J R 1538 (A,97,28) RS1/16SS473J R 1539 (A,98,31) RAB4C681J Circuit Symbol and No. Part No. R 1540 (B,97,28) RS1/16SS473J R 1541 (A,70,34) RAB4C681J R 1542 (B,97,30) RS1/16SS473J R 1543 (B,97,29) RS1/16SS473J R 1544 (B,97,31) RS1/16SS473J R 1545 (B,94,29) RS1/16S473J R 1546 (A,66,42) RS1/16SS473J R 1547 (A,97,33) RS1/16SS473J R 1548 (A,98,36) RAB4C681J R 1549 (B,94,28) RS1/16S473J R 1550 (A,70,41) RAB4C101J R 1551 (A,98,40) RAB4C681J R 1552 (B,104,41) RS1/16SS472J R 1554 (B,103,42) RS1/16SS473J R 1555 (B,79,40) RS1/16SS473J R 1557 (A,90,46) RS1/16SS473J R 1558 (A,76,47) RAB4C681J R 1559 (A,79,47) RAB4C681J R 1561 (A,92,46) RS1/16SS681J R 1562 (A,75,50) RS1/16SS104J R 1563 (A,93,46) RS1/16SS0R0J R 1564 (A,76,50) RS1/16SS104J R 1565 (A,74,50) RS1/16SS104J R 1566 (B,95,51) RS1/16SS473J R 1567 (B,97,50) RS1/16SS101J R 1568 (A,96,16) RS1/16SS681J R 1569 (B,97,19) RS1/16SS104J R 1570 (A,99,21) RS1/16SS473J R 1601 (B,58,16) RS1/10S620J R 1602 (B,56,16) RS1/10S101J R 1603 (B,60,16) RS1/10S101J R 1604 (B,54,26) RS1/16SS0R0J R 1605 (B,55,26) RS1/16SS0R0J R 1606 (B,53,17) RS1/16SS102J R 1607 (B,96,43) RS1/10S122J R 1608 (B,90,44) RS1/16S332J R 1609 (B,91,40) RS1/16S682J R 1701 (B,39,14) RS1/16SS0R0J R 1702 (B,39,7) RS1/16SS0R0J R 1704 (B,42,23) RS1/16SS0R0J R 1706 (B,34,19) RS1/16SS0R0J R 1709 (B,30,21) RS1/16SS0R0J R 1711 (B,29,20) RS1/16SS0R0J R 1713 (B,28,22) RS1/16SS0R0J R 1714 (B,26,21) RS1/16SS0R0J R 1720 (B,14,18) RS1/16SS0R0J R 1721 (B,9,19) RS1/16SS0R0J R 1722 (B,12,18) RS1/16SS0R0J R 1801 (A,64,35) RS1/16SS101J R 1802 (B,39,75) RS1/16SS102J R 1803 (B,39,77) RS1/16SS103J R 1804 (A,48,102) RS1/16S4701D R 1805 (A,63,33) RS1/16SS471J R 1806 (A,64,40) RS1/16SS103J R 1807 (A,50,98) RS1/10S103J R 1810 (A,36,90) RS1/8S471J R 1811 (A,41,86) RS1/8S471J R 1820 (A,62,39) RS1/16SS473J R 1821 (A,64,29) RS1/16SS102J R 1823 (A,66,27) RS1/16SS472J Circuit Symbol and No. Part No. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 152 1 2 3 4 1 2 3 4 C D F A B E R 1824 (A,63,25) RS1/16S472J R 1825 (A,44,96) RS1/16SS103J R 1826 (A,34,92) RS1/16SS153J R 1827 (B,113,95) RS1/10S0R0J R 1834 (A,86,80) RS1/10S0R0J R 1840 (A,121,65) RS1/16SS0R0J R 1843 (A,131,69) RS1/16SS0R0J R 1844 (A,132,65) RS1/16SS471J R 1846 (B,92,81) RS1/16SS820J R 1847 (B,92,83) RS1/16SS820J R 1848 (B,110,66) RS1/16SS0R0J R 1849 (B,89,86) RS1/16S0R0J R 1850 (B,128,66) RS1/10S181J R 1851 (B,131,65) RS1/10S181J R 1852 (B,133,65) RS1/10S181J R 1853 (B,129,68) RS1/16SS221J R 1862 (B,69,85) RS1/16SS473J R 1863 (B,71,86) RS1/16SS473J R 1864 (B,85,76) RS1/16SS103J R 1865 (B,84,76) RS1/16SS474J R 1866 (B,95,15) RS1/16SS223J R 1867 (B,94,17) RS1/16SS223J R 1880 (B,129,93) RS1/16SS103J R 1881 (B,131,96) RS1/16SS103J R 1882 (B,129,94) RS1/16SS512J R 1883 (B,133,90) RS1/16SS224J R 1884 (B,135,91) RS1/16SS472J R 1885 (B,132,98) RS1/10S221J R 1886 (B,132,103) RS1/8S221J R 1887 (B,136,105) RS1/8S221J R 1888 (B,133,92) RS1/16SS0R0J R 1900 (A,114,78) RS1/10S0R0J R 1901 (A,122,81) RS1/16S221J R 1902 (A,144,64) RS1/10S0R0J R 1903 (A,122,82) RS1/16S471J R 1904 (A,118,79) RS1/16S101J R 1905 (A,118,77) RS1/16S471J R 1906 (A,122,84) RS1/16S223J R 1907 (A,118,80) RS1/16S103J R 1908 (A,132,83) RS1/16S2202D R 1909 (A,132,80) RS1/16S2201D R 1910 (A,130,80) RS1/16S4301D R 1911 (A,139,81) RS1/16SS821J R 1912 (A,139,83) RS1/16SS221J R 1913 (A,144,79) RS1/8S821J R 1914 (A,144,75) RS1/16SS153J R 1915 (A,141,79) RS1/8S821J R 1917 (A,110,71) RS1/16SS0R0J R 1920 (B,136,30) RS1/10S0R0J R 1921 (B,140,30) RS1/10S0R0J R 1922 (B,137,27) RS1/16SS103J R 1923 (A,157,7) RS1/16SS221J R 1924 (A,164,11) RS1/10S121J R 1925 (A,168,11) RS1/10S121J R 1926 (A,168,8) RS1/10S121J R 1927 (B,142,19) RS1/10S0R0J R 1930 (B,137,26) RS1/16SS471J R 1931 (B,135,26) RS1/16SS471J R 1932 (A,160,12) RS1/16SS223J R 1933 (A,162,12) RS1/16SS183J Circuit Symbol and No. Part No. R 1940 (B,140,55) RS1/16SS1R0J R 1941 (B,138,59) RS1/16SS103J R 1942 (B,139,61) RS1/16SS223J R 1943 (B,146,50) RS1/16SS221J R 1944 (B,150,59) RS1/16SS121J R 1945 (B,150,57) RS1/16SS121J R 1946 (B,150,55) RS1/16SS121J R 1949 (B,141,51) RS1/16SS1R0J R 1960 (A,57,41) RS1/16SS101J R 1961 (A,58,38) RS1/16SS471J R 1962 (A,59,40) RS1/16SS103J R 1963 (A,36,92) RS1/10S103J R 4000 (A,37,34) RS1/16SS102J R 4001 (A,46,32) RS1/16SS102J R 4003 (A,36,33) RS1/16SS181J R 4004 (A,36,34) RS1/16SS223J R 4005 (A,35,34) RS1/16SS102J R 4006 (A,47,33) RS1/16SS181J R 4007 (A,47,35) RS1/16SS223J R 4008 (A,49,34) RS1/16SS102J R 4009 (A,32,54) RS1/16SS0R0J R 4010 (A,48,55) RS1/16SS0R0J R 4016 (A,34,56) RS1/16SS101J R 4017 (B,47,63) RS1/16SS224J R 4019 (A,47,58) RS1/16SS101J R 4020 (B,41,63) RS1/16SS224J R 4021 (A,41,56) RS1/16SS0R0J R 4100 (B,40,71) RS1/16SS472J R 4101 (B,46,70) RS1/16SS472J R 4102 (B,46,71) RS1/16SS472J R 4103 (B,40,70) RS1/16SS472J R 4108 (B,37,68) RS1/16SS472J R 4109 (B,36,68) RS1/16SS472J R 4110 (B,37,66) RS1/16SS472J R 4111 (B,41,64) RS1/16SS471J R 4112 (B,49,68) RS1/16SS472J R 4113 (B,48,67) RS1/16SS472J R 4114 (B,49,65) RS1/16SS472J R 4115 (B,50,65) RS1/16SS471J R 4202 (A,82,91) RS1/16SS223J R 4203 (A,85,88) RS1/16SS103J R 4204 (A,81,92) RS1/16SS473J R 4205 (A,43,83) RS1/16SS101J R 4206 (A,41,76) RS1/16SS101J R 4207 (A,46,76) RS1/16SS471J R 4208 (A,37,81) RS1/16SS561J R 4209 (A,37,77) RS1/16SS471J R 4210 (A,29,79) RS1/16SS561J R 4211 (A,90,100) RS1/16SS103J R 4212 (A,86,99) RS1/16SS103J R 4213 (B,20,91) RS1/16SS223J R 4214 (B,13,87) RS1/16SS223J R 4215 (B,14,93) RS1/16SS223J R 4216 (B,19,91) RS1/16SS471J R 4217 (B,12,87) RS1/16SS471J R 4218 (B,13,92) RS1/16SS471J R 4219 (B,16,83) RS1/16SS223J R 4220 (B,16,89) RS1/16SS223J R 4221 (B,12,81) RS1/16SS223J R 4222 (B,17,83) RS1/16SS471J Circuit Symbol and No. Part No. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 153 5 6 7 8 5 6 7 8 C D F A B E R 4223 (B,17,89) RS1/16SS471J R 4224 (B,11,81) RS1/16SS471J R 4225 (A,85,99) RS1/16SS221J R 4226 (A,80,106) RS1/16SS101J R 4227 (A,81,98) RS1/10S102J R 4228 (A,102,102) RS1/16SS103J R 4229 (A,102,103) RS1/16SS103J R 4230 (A,78,90) RS1/16SS391J R 4231 (A,78,89) RS1/16SS391J R 4233 (A,70,100) RS1/16SS102J R 4302 (B,155,40) RS1/16S681J R 4303 (B,156,66) RS1/16S681J R 4304 (B,156,68) RS1/16S681J R 4305 (B,154,71) RS1/16S681J R 4306 (B,156,60) RS1/16S681J R 4308 (B,156,63) RS1/16S681J R 4315 (B,154,26) RS1/16S0R0J R 4409 (B,44,44) RS1/16SS102J R 4412 (B,41,46) RS1/16SS101J R 4413 (B,39,46) RS1/16SS101J R 4414 (B,43,45) RS1/16SS223J R 4415 (B,38,45) RS1/16SS223J R 4416 (B,38,44) RS1/16SS102J R 4500 (B,52,47) RS1/16SS104J R 4501 (B,52,49) RS1/16SS102J R 4502 (B,47,49) RS1/16SS102J R 4503 (B,43,51) RS1/16SS473J R 4504 (B,54,49) RS1/16SS473J R 4505 (B,43,54) RS1/16SS0R0J R 4506 (B,43,52) RS1/16SS473J R 4507 (B,52,51) RS1/16SS473J R 4508 (B,53,54) RS1/16SS0R0J R 4509 (B,43,57) RS1/16SS331J R 4510 (B,51,58) RS1/16SS331J R 4511 (B,51,59) RS1/16SS104J R 4512 (B,45,59) RS1/16SS104J R 4515 (B,59,52) RS1/16SS0R0J R 4600 (A,59,63) RS1/16SS102J CAPACITORS C 1001 (B,16,43) 10µF CCG1171 C 1002 (B,10,46) 10µF CCG1171 C 1003 (A,28,83) 10µF CCG1171 C 1004 (A,21,79) 10µF CCG1171 C 1005 (B,9,78) 10µF CCG1171 C 1006 (B,15,77) 10µF CCG1171 C 1007 (B,13,43) CKSRYB473K50 C 1008 (A,26,78) CKSRYB473K50 C 1009 (B,12,78) CKSRYB473K50 C 1010 (B,14,50) CCSRCK1R0C50 C 1012 (A,26,75) CCSRCK1R0C50 C 1014 (B,11,72) CCSRCK1R0C50 C 1016 (B,15,55) CKSRYB105K10 C 1017 (A,28,71) CKSRYB105K10 C 1018 (B,15,67) CKSRYB105K10 C 1019 (A,16,57) CEVW100M16 C 1020 (A,33,73) CEVW100M16 C 1021 (A,12,63) CEVW100M16 C 1022 (B,15,59) CKSRYB104K16 C 1023 (A,30,72) CKSRYB104K16 Circuit Symbol and No. Part No. C 1024 (B,10,63) CKSRYB104K16 C 1201 (A,12,47) CKSQYB225K10 C 1202 (A,11,47) CKSQYB225K10 C 1203 (B,21,66) CKSQYB225K10 C 1204 (B,19,66) CKSQYB225K10 C 1205 (A,37,68) CKSRYB104K16 C 1206 (A,32,64) CEVW101M16 C 1207 (A,28,60) CKSRYB103K50 C 1208 (B,25,67) CKSRYB104K16 C 1209 (B,26,68) CKSYF106Z10 C 1210 (A,27,50) CKSRYB104K16 C 1211 (A,18,44) CKSRYB104K16 C 1213 (A,19,47) CKSRYB104K16 C 1214 (B,28,60) CKSQYB225K10 C 1215 (A,26,56) CEVW101M16 C 1216 (A,19,45) CKSYF106Z10 C 1217 (A,27,51) CKSRYB103K50 C 1218 (A,20,54) CKSQYB225K10 C 1219 (A,22,63) CKSYF106Z10 C 1222 (A,20,62) CKSRYB104K16 C 1223 (A,17,70) CEVW101M16 C 1224 (A,11,71) CEVW220M6R3 C 1233 (B,24,44) CKSRYB104K16 C 1301 (B,105,55) CKSRYB103K50 C 1302 (B,108,48) CKSRYB103K50 C 1307 (B,109,48) CKSRYB103K50 C 1405 (A,12,99) CKSRYB471K50 C 1406 (A,11,99) CKSRYB471K50 C 1407 (A,9,99) CKSRYB471K50 C 1408 (A,8,99) CKSRYB471K50 C 1409 (A,7,99) CKSRYB471K50 C 1410 (A,5,99) CKSRYB471K50 C 1411 (A,9,95) CKSRYB103K50 C 1450 (B,105,110) CKSRYB102K50 C 1451 (B,104,103) CKSRYB102K50 C 1501 (A,96,51) CEVLW100M16 C 1502 (A,95,47) CKSRYB103K50 C 1503 (B,89,20) CKSSYB104K10 C 1504 (A,94,44) CKSRYB103K50 C 1505 (A,63,18) CKSSYB104K10 C 1506 (B,78,22) CKSSYB104K10 C 1507 (B,78,23) CKSSYB104K10 C 1508 (B,79,26) CKSRYB102K50 C 1509 (B,92,27) CKSRYB104K16 C 1510 (A,70,38) CKSRYB102K50 C 1511 (A,65,44) CKSSYB104K10 C 1512 (A,88,46) CKSRYB105K10 C 1513 (A,83,46) CKSRYB102K50 C 1515 (A,91,46) CKSRYB103K50 C 1516 (A,93,59) CKSRYF104Z25 C 1517 (B,98,48) CKSQYB225K10 C 1519 (A,96,59) CKSRYF104Z25 C 1520 (B,103,52) CKSSYB104K10 C 1521 (B,97,47) CKSSYB103K16 C 1603 (B,61,21) CKSRYB102K50 C 1606 (B,61,22) CKSRYB102K50 C 1608 (B,61,23) CKSRYB104K16 C 1651 (A,53,19) CKSRYB103K50 C 1652 (A,50,19) CKSRYB103K50 C 1653 (A,47,13) CKSRYB104K25 Circuit Symbol and No. Part No. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 154 1 2 3 4 1 2 3 4 C D F A B E C 1709 (B,22,20) CKSSYB104K10 C 1712 (B,24,26) CKSSYB104K10 C 1801 (B,48,75) CKSRYF104Z25 C 1802 (B,48,78) CKSRYB473K25 C 1803 (A,40,97) CKSRYF104Z25 C 1804 (B,44,100) CKSRYF104Z25 C 1806 (B,44,116) CKSQYF103Z50 C 1807 (B,46,116) CKSQYF104Z50 C 1810 (A,43,87) CKSRYF104Z25 C 1811 (B,57,101) CKSRYB471K50 C 1812 (B,63,115) CKSRYB471K50 C 1813 (B,55,100) CKSRYB471K50 C 1814 (B,61,115) CKSRYB471K50 C 1815 (B,54,100) CKSRYB471K50 C 1816 (B,60,115) CKSRYB471K50 C 1817 (B,53,100) CKSRYB471K50 C 1818 (B,59,115) CKSRYB471K50 C 1819 (B,43,100) CKSRYB471K50 C 1824 (B,41,84) CKSRYF104Z25 C 1825 (A,60,35) CKSRYB105K10 C 1826 (A,43,96) CKSRYF104Z25 C 1828 (B,39,85) CKSRYF104Z25 C 1830 (A,87,77) CKSQYB104K25 C 1831 (A,99,73) CEVLW330M25 C 1832 (A,86,77) CKSRYB104K25 C 1833 (A,92,73) CEVLW330M25 C 1840 (A,140,55) CEVW101M16 C 1841 (A,122,69) CKSRYB103K50 C 1843 (A,104,63) CEVW101M16 C 1845 (A,128,71) CKSRYB103K50 C 1847 (B,95,82) CKSRYB104K25 C 1850 (B,129,71) CKSRYB473K50 C 1851 (A,114,65) CEVLW101M10 C 1852 (B,110,69) CKSRYB103K50 C 1855 (B,132,95) CKSRYB472K50 C 1880 (B,132,91) CKSRYB104K16 C 1881 (B,144,92) CKSRYB103K50 C 1882 (A,145,93) CEVW100M16 C 1883 (B,143,94) CKSRYB103K50 C 1884 (A,94,92) CEVW101M16 C 1900 (A,126,82) CKSRYB104K25 C 1901 (A,128,76) CEVW101M16 C 1902 (A,118,81) CKSRYB102K50 C 1903 (A,150,87) CEVW101M16 C 1904 (A,129,80) CKSRYB103K50 C 1905 (A,130,83) CKSRYB102K50 C 1906 (A,143,86) CEVW101M16 C 1907 (A,138,71) CKSRYB103K50 C 1908 (A,140,74) CKSRYB104K25 C 1910 (A,116,73) CEVLW101M10 C 1911 (B,125,77) CKSRYB103K50 C 1912 (B,132,77) CKSRYB104K25 C 1920 (A,148,25) CEVW221M10 C 1921 (B,134,22) CKSRYB473K50 C 1922 (A,135,16) CEVW101M16 C 1923 (A,170,9) CKSRYB102K50 C 1924 (A,135,8) CEVW100M16 C 1925 (A,157,10) CKSRYB473K50 C 1926 (A,137,25) CEVW221M10 C 1940 (B,141,56) CKSRYB104K16 Circuit Symbol and No. Part No. C 1942 (B,142,47) CKSRYB104K25 C 1944 (B,144,47) CKSRYB473K50 C 1960 (A,35,102) CKSRYF103Z50 C 4000 (A,44,33) CKSRYB152K50 C 4001 (A,39,33) CKSRYB152K50 C 4002 (A,31,39) CKSRYB102K50 C 4003 (A,30,33) CEVW470M16 C 4004 (A,31,37) CKSRYB104K16 C 4005 (A,36,37) CKSRYB105K10 C 4006 (A,37,37) CKSRYB105K6R3 C 4007 (A,39,37) CKSRYB105K6R3 C 4008 (A,40,37) CKSRYB104K16 C 4009 (A,43,37) CKSRYB104K16 C 4010 (A,44,37) CKSRYB105K6R3 C 4011 (A,34,37) CKSRYB105K10 C 4012 (A,45,37) CKSRYB105K6R3 C 4013 (A,46,37) CKSRYB105K10 C 4014 (A,48,37) CKSRYB105K10 C 4015 (A,30,41) CKSYB475K16 C 4016 (A,30,43) CKSYB475K16 C 4017 (A,30,46) CKSYB475K16 C 4018 (A,30,48) CKSYB475K16 C 4019 (A,50,41) CKSYB475K16 C 4020 (A,50,43) CKSYB475K16 C 4021 (A,50,46) CKSYB475K16 C 4022 (A,50,48) CKSYB475K16 C 4023 (A,33,52) CCSRCH100D50 C 4024 (A,34,54) CCSRCH100D50 C 4025 (A,35,55) CCSRCH100D50 C 4026 (A,40,60) CEVW100M16 C 4027 (A,42,55) CKSRYB104K16 C 4034 (A,43,55) CKSRYB104K16 C 4035 (A,45,55) CCSRCH100D50 C 4036 (A,46,55) CCSRCH100D50 C 4037 (A,47,52) CCSRCH100D50 C 4038 (A,38,57) CKSRYB104K16 C 4100 (B,36,62) 10µF CCG1138 C 4101 (B,56,64) 10µF CCG1138 C 4102 (B,51,63) CKSRYB105K6R3 C 4103 (B,36,66) CKSRYB105K6R3 C 4106 (B,38,69) CCSRCH101J50 C 4107 (B,38,65) CCSRCH101J50 C 4108 (B,48,69) CCSRCH101J50 C 4109 (B,48,65) CCSRCH101J50 C 4110 (B,43,71) CKSRYB104K16 C 4111 (A,47,67) CEVW100M16 C 4200 (A,48,79) CEVW100M16 C 4201 (A,43,73) CEVW100M16 C 4202 (A,49,73) CEVW100M16 C 4203 (A,39,73) CEVW100M16 C 4204 (A,41,79) CEVW100M16 C 4205 (A,33,79) CEVW100M16 C 4206 (A,70,98) CKSRYB105K10 C 4207 (A,70,96) CKSRYB105K10 C 4208 (A,77,98) CKSRYB105K10 C 4209 (A,75,99) CKSRYB105K10 C 4210 (A,67,97) CKSRYB105K10 C 4211 (A,74,100) CKSRYB105K10 C 4212 (A,76,96) CKSRYB105K10 C 4213 (A,78,98) CKSRYB105K10 Circuit Symbol and No. Part No. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 155 5 6 7 8 5 6 7 8 C D F A B E C 4215 (A,91,105) 10µF CCG1138 C 4216 (A,72,91) CKSRYB104K25 C 4217 (A,70,103) CEHVW100M16 C 4218 (B,19,93) CKSRYB222K50 C 4219 (B,12,89) CKSRYB222K50 C 4220 (B,13,94) CKSRYB222K50 C 4224 (B,17,87) CKSRYB222K50 C 4225 (B,12,83) CKSRYB222K50 C 4229 (B,16,82) CKSRYB222K50 C 4230 (A,77,105) CKSYB475K16 C 4231 (A,79,105) CKSYB475K16 C 4232 (A,58,79) 2200µF/16V CCH1659(P35) C 4233 (A,85,104) CEHVW330M16 C 4234 (A,83,94) CKSSYF104Z16 C 4235 (A,93,105) CKSRYB473K50 C 4236 (A,71,86) CEVW470M16 C 4302 (B,155,36) CKSYB475K16 C 4303 (B,155,42) CKSRYB103K50 C 4304 (B,152,36) CKSRYB103K50 C 4306 (A,150,37) CEVW470M6R3 C 4307 (A,142,37) CEVW220M16 C 4308 (B,154,73) CKSRYB103K50 C 4309 (A,149,65) CEVW221M10 C 4310 (A,149,76) CEVW221M10 C 4311 (A,151,81) CKSRYB103K50 C 4316 (A,140,43) CKSRYB103K50 C 4317 (A,141,49) CKSRYB104K16 C 4410 (B,47,43) CKSRYB105K10 C 4411 (B,44,43) CKSRYB105K10 C 4412 (B,40,45) CKSRYB105K10 C 4413 (B,40,43) CKSRYB105K10 C 4415 (A,45,28) CEVW100M16 C 4416 (A,38,28) CEVW220M16 C 4500 (B,50,48) CKSRYB105K6R3 C 4502 (B,50,50) CKSRYB103K50 C 4503 (B,45,50) CKSRYB103K50 C 4504 (B,42,53) CCSRCH471J50 C 4505 (B,50,52) CCSRCH221J50 C 4506 (B,45,52) CCSRCH221J50 C 4507 (B,54,52) CCSRCH471J50 C 4508 (B,46,58) CKSRYF104Z25 C 4509 (B,42,55) CKSRYB105K6R3 C 4510 (B,53,57) CKSRYB105K6R3 C 4511 (A,53,62) CEVW220M16 C 4601 (A,53,55) CEVW101M16 MONI_PANEL Unit Consists of Monitor PCB Keyboard PCB Panel PCB HIJ Unit Number:CWM9920 Unit Name:MONI_PANEL Unit MISCELLANEOUS Circuit Symbol and No. Part No. IC 5001 (A,28,51) IC TC90A64AF-P IC 5026 (A,62,27) IC TC7SH00FUS1 IC 5061 (A,24,70) IC TC7SH08FUS1 IC 5151 (A,53,33) IC NJM2138V IC 5181 (A,44,17) IC NJM082BV IC 5331 (A,67,77) IC OZ961ISN IC 5333 (A,59,65) IC TC7SH08FUS1 IC 5601 (A,91,53) IC PE5479A IC 5602 (A,79,43) IC S-80835CNNB-B8U IC 5651 (A,73,55) IC S-29221BROI-J8T1 IC 5700 (A,87,102) IC SBX3050-01 IC 5701 (A,88,90) IC TC7SH08FUS1 IC 5702 (A,86,156) IC TPS850 IC 5841 (A,140,25) IC R1130H251B IC 5851 (A,116,25) IC BD6171KV IC 5901 (A,37,80) IC NJM2903V Q 5002 (A,43,64) Transistor 2SC4617 Q 5101 (A,52,58) Transistor 2SC4617 Q 5102 (A,49,66) Transistor 2SA1774 Q 5103 (A,51,63) Transistor 2SC4617 Q 5151 (A,44,38) Transistor UMZ1N Q 5152 (A,39,35) Transistor UMZ1N Q 5153 (A,39,31) Transistor UMZ1N Q 5154 (A,54,26) Transistor UMZ1N Q 5155 (A,47,26) Transistor UMZ1N Q 5156 (A,39,26) Transistor UMZ1N Q 5182 (A,38,21) Transistor UMX2N Q 5183 (A,38,15) Transistor UMT2N Q 5331 (A,74,72) Transistor 2SC4617 Q 5332 (A,76,72) Transistor DTA144EE Q 5333 (A,80,75) FET TS8M1 Q 5334 (A,80,79) FET TS8M1 Q 5342 (A,63,73) Transistor 2SC4617 Q 5343 (A,60,73) Transistor 2SC4617 Q 5351 (A,54,82) Transistor 2SC4097 Q 5371 (A,65,62) Transistor 2SC4617 Q 5372 (A,68,61) Transistor 2SC4617 Q 5373 (A,68,65) Transistor 2SA1774 Q 5375 (A,75,67) Transistor UMX2N Q 5380 (A,71,64) Transistor 2SC4617 Q 5603 (A,86,40) Transistor 2SC4617 Q 5681 (A,68,9) Transistor UMF5N Q 5682 (A,68,13) Transistor UMF5N Q 5683 (A,72,8) Transistor FMG12 Q 5701 (A,86,140) Transistor 2SC4617 Q 5702 (A,86,143) Transistor 2SA1774 Q 5703 (A,87,151) Transistor 2SA1774 Q 5831 (A,118,12) FET RSQ035P03 Q 5832 (A,108,13) FET RSQ035P03 D 5331 (A,73,75) Diode UDZS6R2(B) D 5332 (A,74,78) Diode UDZS6R2(B) D 5333 (A,83,71) Diode MA147 D 5334 (A,82,69) Diode MA147 D 5335 (A,79,69) Diode UDZS5R6(B) D 5336 (A,57,78) Diode UDZS6R2(B) D 5337 (A,62,83) Diode RB751V40 D 5338 (A,57,83) Diode UDZS5R6(B) D 5371 (A,63,67) Diode UDZS8R2(B) D 5601 (A,108,40) Diode RB500V-40 D 5611 (A,120,53) Diode UDZS5R6(B) Circuit Symbol and No. Part No. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 156 1 2 3 4 1 2 3 4 C D F A B E D 5612 (A,122,50) Diode UMZ6R8N D 5613 (A,118,49) Diode UMZ6R8N D 5614 (A,122,45) Diode UMZ6R8N D 5615 (A,118,44) Diode UMZ6R8N D 5681 (A,71,13) Diode 1SS355 D 5683 (A,9,22) Diode UDZS5R6(B) D 5684 (A,9,28) Diode UDZS5R6(B) D 5700 (A,8,9) LED SML-310PT(KL) D 5701 (A,18,9) LED SML-310PT(KL) D 5702 (A,75,13) LED SML-310PT(KL) D 5703 (A,41,8) LED SML-310PT(KL) D 5704 (A,32,8) LED SML-310PT(KL) D 5705 (A,50,8) LED SML-310PT(KL) D 5706 (A,75,3) LED SML-310PT(KL) D 5707 (A,86,4) LED SML-310PT(KL) D 5708 (A,8,164) LED SML-310PT(KL) D 5709 (A,75,164) LED SML-310PT(KL) D 5710 (A,18,164) LED SML-310PT(KL) D 5711 (A,86,13) LED SML-310PT(KL) D 5712 (A,85,164) LED SML-310PT(KL) D 5713 (A,32,165) LED SML-310PT(KL) D 5714 (A,64,10) LED CL-190UB2-X D 5715 (A,66,167) LED CL-190UB2-X D 5716 (A,50,165) LED SML-310PT(KL) D 5717 (A,66,4) LED CL-190UB2-X D 5718 (A,64,162) LED CL-190UB2-X D 5835 (A,136,25) Diode RB500V-40 D 5851 (A,105,6) Diode RB160M-30 D 5861 (A,119,7) Diode RSX201L-30 D 5862 (A,105,17) Diode RB548W D 5863 (A,105,20) Diode RB548W D 5864 (A,116,34) Diode RB548W D 5865 (A,120,34) Diode RB548W D 5866 (A,123,34) Diode RB548W D 5901 (A,46,15) LED SML-310PT(KL) D 5902 (A,46,23) LED SML-310PT(KL) D 5903 (A,15,4) LED SML-310PT(KL) D 5904 (A,15,9) LED SML-310PT(KL) D 5905 (A,13,85) LED SML-310PT(KL) D 5906 (A,39,85) LED SML-310PT(KL) L 5001 (A,18,39) Inductor CTF1306 L 5002 (A,22,37) Inductor CTF1306 L 5003 (A,26,37) Inductor CTF1306 L 5004 (A,28,38) Inductor CTF1306 L 5005 (A,28,68) Inductor-Array CTF1421 L 5006 (A,23,66) Inductor-Array CTF1421 L 5008 (A,26,67) Inductor CTF1306 L 5009 (A,23,37) Ferrite Bead CTF1528 L 5011 (A,20,36) Inductor CTF1306 L 5012 (A,25,37) Ferrite Bead CTF1528 L 5013 (A,29,65) Ferrite Bead CTF1528 L 5014 (A,24,64) Ferrite Bead CTF1528 L 5015 (A,20,65) Inductor CTF1306 L 5016 (A,16,48) Ferrite Bead CTF1528 L 5071 (A,67,33) Inductor LCKAW100J2520 L 5074 (A,43,42) Inductor LCKBW1R0M2520 L 5075 (A,52,42) Inductor LCKBW100K2520 L 5078 (A,50,46) Inductor LCKAW100J2520 L 5079 (A,46,49) Inductor CTF1306 L 5101 (A,130,5) Inductor LCKAW100J2520 Circuit Symbol and No. Part No. L 5151 (A,59,17) Inductor LCKAW100J2520 L 5152 (A,55,15) Inductor LCKAW100J2520 L 5181 (A,55,12) Inductor LCKAW101J2520 L 5182 (A,51,11) Inductor LCKAW101J2520 L 5311 (A,51,76) Inductor CTH1256 L 5601 (A,106,44) Inductor LCKBW100K2520 L 5606 (A,107,50) Inductor CTF1306 L 5607 (A,106,52) Inductor CTF1306 L 5801 (A,20,32) Inductor LCKAW100J2520 L 5802 (A,23,32) Inductor LCKAW100J2520 L 5803 (A,27,32) Inductor LCKAW100J2520 L 5804 (A,30,32) Inductor LCKAW100J2520 L 5841 (A,139,15) Choke Coil 10µH CTH1249 L 5843 (A,129,32) Inductor CTF1635 L 5851 (A,123,12) Choke Coil 18µH CTH1250 L 5852 (A,93,14) Choke Coil 10µH CTH1259 L 5862 (A,103,13) Choke Coil 68µH CTH1318 L 5863 (A,98,21) Inductor DTL1096 L 5864 (A,98,9) Inductor CTF1635 L 5865 (A,125,37) Inductor CTF1635 L 5901 (A,45,73) Inductor LCKAW100J2520 T 5331 (A,105,78) Transformer CTT1119 TH5601 (A,77,7) Thermistor CCX1051 X 5001 (A,34,69) Crystal Resonator 42MHz CSS1604 X 5601 (A,89,40) Radiator 12.58MHz CSS1601 S 5700 (A,69,6) Push Switch CSG1155 S 5701 (A,62,6) Push Switch CSG1126 S 5702 (A,53,8) Push Switch CSG1155 S 5703 (A,29,8) Push Switch CSG1155 S 5704 (A,16,6) Push Switch CSG1155 S 5709 (A,77,166) Push Switch CSG1155 S 5710 (A,86,166) Push Switch CSG1155 S 5713 (A,80,8) Switch(SELECT) CSX1075 S 5715 (A,29,165) Push Switch CSG1155 S 5716 (A,16,167) Push Switch CSG1155 S 5717 (A,6,167) Push Switch CSG1155 S 5718 (A,6,6) Push Switch CSG1155 S 5719 (A,62,166) Push Switch CSG1126 S 5720 (A,55,166) Push Switch CSG1155 S 5901 (A,9,85) Push Switch CSG1126 S 5902 (A,44,85) Push Switch CSG1126 VR5331 (A,69,83) Semi-fixed 15kΩ(B) CCP1424 RESISTORS R 5001 (A,27,36) RS1/16S101J R 5002 (A,21,35) RS1/16S470J R 5003 (A,29,36) RS1/16S101J R 5004 (A,33,35) RS1/16S101J R 5005 (A,44,45) RS1/16S473J R 5006 (A,47,46) RS1/16S392J R 5009 (A,44,62) RS1/16S152J R 5010 (A,42,67) RS1/16S331J R 5012 (A,32,64) RS1/16S105J R 5013 (A,34,65) RS1/16S391J R 5018 (A,22,68) RS1/16S101J R 5022 (A,20,67) RS1/16S101J R 5024 (A,14,60) RS1/16S333J R 5025 (A,16,39) RS1/16S101J R 5026 (A,30,36) RS1/16S0R0J Circuit Symbol and No. Part No. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 157 5 6 7 8 5 6 7 8 C D F A B E R 5027 (A,17,31) RS1/16S101J R 5028 (A,64,24) RS1/16S101J R 5029 (A,65,28) RS1/16S102J R 5030 (A,18,35) RS1/16S101J R 5037 (A,25,82) RS1/16S472J R 5038 (A,27,82) RS1/16S473J R 5039 (A,15,39) RS1/16S101J R 5040 (A,24,82) RS1/16S473J R 5061 (A,20,71) RS1/16S473J R 5101 (A,52,55) RS1/16S1502F R 5102 (A,49,56) RS1/16S1003F R 5103 (A,49,58) RS1/16S681J R 5104 (A,51,60) RS1/16S331J R 5105 (A,52,66) RS1/16S0R0J R 5107 (A,52,51) RS1/16S392J R 5108 (A,52,60) RS1/16S331J R 5109 (A,49,64) RS1/16S391J R 5110 (A,52,65) RS1/16S391J R 5150 (A,39,28) RS1/16S183J R 5152 (A,48,35) RS1/16S3901F R 5153 (A,45,35) RS1/16S1501F R 5154 (A,54,30) RS1/16S102J R 5155 (A,51,30) RS1/16S102J R 5156 (A,45,31) RS1/16S1501F R 5157 (A,48,30) RS1/16S3901F R 5160 (A,58,33) RS1/16S1002F R 5161 (A,60,30) RS1/16S1802F R 5162 (A,57,30) RS1/16S102J R 5163 (A,53,38) RS1/16S3901F R 5164 (A,50,38) RS1/16S1501F R 5165 (A,47,38) RS1/16S102J R 5166 (A,41,38) RS1/16S272J R 5167 (A,42,35) RS1/16S102J R 5168 (A,37,35) RS1/16S272J R 5169 (A,42,31) RS1/16S102J R 5170 (A,37,31) RS1/16S272J R 5171 (A,52,27) RS1/16S331J R 5172 (A,56,24) RS1/16S103J R 5174 (A,44,27) RS1/16S331J R 5175 (A,48,24) RS1/16S103J R 5177 (A,36,26) RS1/16S331J R 5178 (A,40,24) RS1/16S103J R 5180 (A,35,29) RS1/16S243J R 5181 (A,42,23) RS1/16S3002F R 5182 (A,47,22) RS1/16S223J R 5183 (A,45,22) RS1/16S1203F R 5184 (A,47,19) RS1/16S1602F R 5185 (A,48,14) RS1/16S1502F R 5186 (A,42,21) RS1/16S1002F R 5187 (A,42,18) RS1/16S1002F R 5188 (A,41,16) RS1/16S101J R 5189 (A,36,19) RS1/16S153J R 5190 (A,40,21) RS1/16S100J R 5191 (A,36,14) RS1/16S153J R 5192 (A,41,14) RS1/16S100J R 5193 (A,38,13) RS1/16S0R0J R 5194 (A,39,18) RS1/16S0R0J R 5331 (A,57,72) RS1/16S105J R 5332 (A,71,73) RS1/16S473J R 5333 (A,78,72) RS1/16S183J Circuit Symbol and No. Part No. R 5334 (A,71,69) RS1/16S102J R 5335 (A,59,70) RS1/16S102J R 5336 (A,79,72) RS1/16S513J R 5337 (A,61,79) RS1/16S105J R 5338 (A,74,75) RS1/16S103J R 5339 (A,66,83) RS1/16S563J R 5340 (A,73,79) RS1/16S103J R 5342 (A,78,69) RS1/16S511J R 5343 (A,79,66) RS1/16S821J R 5344 (A,57,74) RS1/16S473J R 5350 (A,60,61) RS1/16S471J R 5351 (A,57,81) RS1/16S332J R 5360 (A,57,75) RS1/16S104J R 5361 (A,57,77) RS1/16S103J R 5371 (A,63,64) RS1/16S101J R 5372 (A,71,62) RS1/16S103J R 5373 (A,73,65) RS1/16S471J R 5374 (A,72,67) RS1/16S101J R 5375 (A,64,64) RS1/16S104J R 5376 (A,67,67) RS1/16S103J R 5377 (A,68,63) RS1/16S473J R 5378 (A,71,66) RS1/16S101J R 5379 (A,63,61) RS1/16S824J R 5602 (A,103,56) RS1/16S471J R 5603 (A,110,52) RS1/16S473J R 5604 (A,107,49) RS1/16S471J R 5605 (A,104,59) RS1/16S471J R 5606 (A,103,53) RAB4CQ471J R 5607 (A,103,57) RS1/16S471J R 5608 (A,102,50) RS1/16S471J R 5609 (A,102,47) RS1/16S471J R 5610 (A,89,64) RS1/16S471J R 5611 (A,94,64) RS1/16S470J R 5612 (A,92,64) RS1/16S470J R 5613 (A,96,64) RS1/16S272J R 5614 (A,91,64) RS1/16S272J R 5619 (A,93,39) RS1/16S473J R 5621 (A,93,40) RS1/16S223J R 5622 (A,84,38) RS1/16S473J R 5623 (A,97,64) RS1/16S473J R 5624 (A,104,61) RAB4CQ473J R 5625 (A,79,46) RS1/16S473J R 5626 (A,75,50) RS1/16S473J R 5627 (A,101,43) RAB4CQ473J R 5628 (A,81,44) RS1/16S0R0J R 5629 (A,101,45) RS1/16S1502D R 5630 (A,97,42) RAB4CQ471J R 5631 (A,30,76) RS1/16S104J R 5632 (A,30,77) RS1/16S104J R 5633 (A,30,79) RS1/16S104J R 5634 (A,30,81) RS1/16S473J R 5637 (A,84,39) RS1/16S471J R 5642 (A,79,51) RS1/16S473J R 5646 (A,77,51) RS1/16S473J R 5651 (A,79,56) RAB4CQ471J R 5652 (A,79,53) RS1/16S471J R 5655 (A,80,59) RS1/16S473J R 5657 (A,94,37) RS1/16S0R0J R 5659 (A,79,58) RS1/16S222J R 5681 (A,9,26) RS1/16S104J Circuit Symbol and No. Part No. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 158 1 2 3 4 1 2 3 4 C D F A B E R 5682 (A,9,21) RS1/16S104J R 5683 (A,74,12) RS1/16S102J R 5684 (A,75,12) RS1/16S102J R 5685 (A,66,7) RS1/16S103J R 5686 (A,66,10) RS1/16S103J R 5687 (A,66,12) RS1/16S103J R 5688 (A,66,15) RS1/16S103J R 5700 (A,85,91) RS1/16S470J R 5701 (A,88,85) RS1/16S470J R 5702 (A,11,12) RS1/16SS101J R 5703 (A,48,11) RS1/16SS101J R 5704 (A,49,4) RS1/16SS101J R 5705 (A,74,163) RS1/16SS101J R 5706 (A,89,158) RS1/16SS121J R 5707 (A,38,164) RS1/16SS101J R 5708 (A,51,13) RS1/16SS821J R 5709 (A,70,12) RS1/16S393J R 5710 (A,67,12) RS1/16S203J R 5711 (A,62,12) RS1/16S123J R 5712 (A,72,9) RS1/16S124J R 5713 (A,72,6) RS1/16S393J R 5714 (A,82,166) RS1/16S203J R 5715 (A,81,167) RS1/16S123J R 5716 (A,11,165) RS1/16S124J R 5717 (A,20,165) RS1/16S393J R 5718 (A,36,167) RS1/16S203J R 5719 (A,57,167) RS1/16S123J R 5720 (A,72,13) RS1/16S124J R 5721 (A,88,141) RS1/16S472J R 5722 (A,88,144) RS1/16S223J R 5724 (A,11,7) RS1/16S124J R 5725 (A,20,8) RS1/16S393J R 5726 (A,38,6) RS1/16S203J R 5727 (A,41,6) RS1/16S123J R 5731 (A,89,154) RS1/16SS121J R 5732 (A,71,165) RS1/16SS821J R 5733 (A,37,165) RS1/16SS101J R 5734 (A,89,149) RS1/16S104J R 5735 (A,87,153) RS1/16S124J R 5736 (A,88,156) RS1/16SS121J R 5737 (A,88,138) RS1/16S473J R 5738 (A,89,152) RS1/16S103J R 5739 (A,86,138) RS1/16S473J R 5740 (A,35,164) RS1/16SS101J R 5741 (A,75,162) RS1/16SS101J R 5742 (A,51,3) RS1/16SS101J R 5743 (A,49,11) RS1/16SS101J R 5744 (A,11,11) RS1/16SS101J R 5745 (A,85,161) RS1/16SS101J R 5746 (A,34,166) RS1/16SS101J R 5747 (A,78,163) RS1/16SS820J R 5748 (A,53,3) RS1/16SS820J R 5749 (A,50,11) RS1/16SS820J R 5750 (A,11,10) RS1/16SS820J R 5751 (A,83,162) RS1/16SS101J R 5752 (A,72,167) RS1/16SS681J R 5753 (A,52,12) RS1/16SS681J R 5802 (A,17,22) RS1/16S0R0J R 5803 (A,35,21) RS1/16S333J R 5802 (A,17,22) RS1/16S0R0J Circuit Symbol and No. Part No. R 5803 (A,35,21) RS1/16S333J R 5804 (A,51,24) RS1/16S0R0J R 5805 (A,45,24) RS1/16S0R0J R 5806 (A,35,26) RS1/16S0R0J R 5835 (A,142,21) RS1/16S684J R 5840 (A,127,37) RS1/16S0R0J R 5861 (A,124,21) RS1/16S333J R 5862 (A,130,26) RS1/16S1001D R 5863 (A,125,25) RS1/16S182J R 5864 (A,128,26) RS1/16S682J R 5865 (A,132,25) RS1/16S201J R 5866 (A,133,26) RS1/16S6801F R 5867 (A,123,28) RS1/16S2001F R 5868 (A,125,29) RS1/16S5100F R 5869 (A,128,22) RS1/16S102J R 5870 (A,128,18) RS1/16S1001D R 5871 (A,130,22) RS1/16S1600D R 5872 (A,131,20) RS1/16S2700D R 5873 (A,108,22) RS1/16S3303D R 5874 (A,108,23) RS1/16S1802F R 5875 (A,105,23) RS1/16S821J R 5876 (A,109,25) RS1/16S5102D R 5877 (A,125,34) RS1/16S2202F R 5878 (A,124,32) RS1/16S1802F R 5879 (A,121,31) RS1/16S1002F R 5880 (A,115,16) RS1/16S563J R 5881 (A,77,37) RS1/16S0R0J R 5883 (A,81,37) RS1/16S0R0J R 5884 (A,117,17) RS1/16S150J R 5885 (A,121,18) RS1/16S150J R 5886 (A,124,17) RS1/16S273J R 5890 (A,123,25) RS1/16S684J R 5901 (A,40,77) RS1/16S103J R 5902 (A,40,74) RS1/16S103J R 5903 (A,33,83) RS1/16S392J R 5904 (A,34,83) RS1/16S912J R 5905 (A,33,80) RS1/16S2703F R 5906 (A,40,84) RS1/16S153J R 5907 (A,38,83) RS1/16S153J R 5951 (A,43,15) RS1/16S471J R 5952 (A,31,19) RS1/16S471J R 5953 (A,15,80) RS1/10S911J R 5954 (A,33,78) RS1/10S911J R 5955 (A,40,15) RS1/16S471J R 5956 (A,34,19) RS1/16S471J R 5957 (A,19,80) RS1/10S102J R 5958 (A,30,77) RS1/10S102J R 5959 (A,37,15) RS1/16S471J R 5960 (A,37,19) RS1/16S471J CAPACITORS C 5001 (A,20,38) CKSRYB105K6R3 C 5002 (A,24,38) CKSSYF104Z16 C 5003 (A,31,38) CKSSYF104Z16 C 5004 (A,33,38) CKSSYF104Z16 C 5005 (A,32,37) CKSSYF104Z16 C 5006 (A,34,38) CKSSYF104Z16 C 5007 (A,36,38) CKSSYF104Z16 C 5008 (A,39,37) CKSSYF104Z16 C 5009 (A,40,38) CKSSYF104Z16 Circuit Symbol and No. Part No. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 159 5 6 7 8 5 6 7 8 C D F A B E C 5010 (A,39,40) CKSSYF104Z16 C 5011 (A,41,43) CKSSYF104Z16 C 5012 (A,40,44) CKSSYF104Z16 C 5013 (A,42,46) CKSRYB392K50 C 5015 (A,44,47) CKSRYB105K6R3 C 5016 (A,40,48) CKSSYF104Z16 C 5017 (A,41,49) CKSSYF104Z16 C 5018 (A,44,50) CKSRYB104K50 C 5019 (A,44,51) CKSRYB104K50 C 5020 (A,44,54) CKSRYB104K50 C 5021 (A,40,52) CKSSYF104Z16 C 5022 (A,46,57) CKSSYF104Z16 C 5023 (A,45,57) CKSSYF104Z16 C 5024 (A,44,57) CKSSYF104Z16 C 5025 (A,41,53) CKSSYF104Z16 C 5026 (A,41,54) CKSSYF104Z16 C 5027 (A,41,55) CKSSYF104Z16 C 5028 (A,41,56) CKSSYF104Z16 C 5029 (A,41,57) CKSSYF104Z16 C 5030 (A,44,60) CKSRYB104K50 C 5031 (A,43,57) CKSSYF104Z16 C 5032 (A,41,58) CKSSYF104Z16 C 5033 (A,41,59) CKSSYF104Z16 C 5034 (A,41,60) CKSSYF104Z16 C 5035 (A,43,66) CKSRYB103K50 C 5036 (A,45,64) CCSRCH4R0C50 C 5037 (A,39,62) CKSSYF104Z16 C 5040 (A,39,63) CKSSYF104Z16 C 5042 (A,37,64) CCSRCH181J50 C 5045 (A,36,67) CCSRCH9R0D50 C 5046 (A,33,66) CCSRCH9R0D50 C 5047 (A,30,63) CKSSYF104Z16 C 5048 (A,29,64) CKSSYF104Z16 C 5049 (A,24,63) CKSSYF104Z16 C 5050 (A,20,64) CKSRYB105K6R3 C 5051 (A,16,55) CKSSYF104Z16 C 5052 (A,16,47) CKSSYF104Z16 C 5054 (A,24,34) CCSRCH101J50 C 5055 (A,15,61) CKSRYB104K50 C 5056 (A,18,68) CCSRCH271J50 C 5057 (A,32,35) CCSSCH220J50 C 5061 (A,21,71) CKSRYB104K50 C 5063 (A,62,29) CKSRYB104K50 C 5065 (A,61,25) CCSRCH120J50 C 5071 (A,56,42) CSZS100M10 C 5074 (A,45,41) CKSRYB105K6R3 C 5075 (A,54,41) CKSRYB105K6R3 C 5076 (A,48,42) 68µF/6.3V CCH1440 C 5081 (A,57,49) CCSRCH101J50 C 5082 (A,57,50) CCSRCH101J50 C 5083 (A,57,52) CCSRCH101J50 C 5101 (A,51,49) CKSYF106Z10 C 5102 (A,49,60) CCSRCH470J50 C 5103 (A,49,62) CCSRCH470J50 C 5104 (A,52,56) CKSRYB104K50 C 5105 (A,50,53) CSZS100M10 C 5151 (A,63,33) CSZSR220M16 C 5152 (A,48,32) CKSRYB103K50 C 5153 (A,47,35) CCSRCH4R0C50 C 5154 (A,47,30) CCSRCH4R0C50 Circuit Symbol and No. Part No. C 5155 (A,52,38) CCSRCH4R0C50 C 5156 (A,60,33) CKSRYB104K50 C 5160 (A,44,35) CKSRYB104K50 C 5161 (A,44,31) CKSRYB104K50 C 5162 (A,49,38) CKSRYB104K50 C 5163 (A,57,28) CKSRYB105K6R3 C 5164 (A,50,28) CKSRYB105K6R3 C 5165 (A,42,28) CKSRYB105K6R3 C 5166 (A,36,28) CKSRYB104K50 C 5167 (A,47,28) CKSRYB104K50 C 5168 (A,54,28) CKSRYB104K50 C 5169 (A,35,31) CKSRYB103K50 C 5170 (A,55,18) CSZSR220M16 C 5171 (A,55,22) CSZSR220M16 C 5181 (A,51,20) CSZSR220M16 C 5182 (A,48,19) CKSRYB104K50 C 5183 (A,51,15) CSZSR4R7M25 C 5184 (A,48,16) CKSRYB104K50 C 5186 (A,48,22) CKSRYB104K50 C 5188 (A,47,16) CKSRYB104K50 C 5311 (A,47,83) 10µF DCH1165 C 5332 (A,49,83) 10µF DCH1165 C 5334 (A,58,83) CKSRYB104K50 C 5335 (A,52,83) CKSQYB105K16 C 5336 (A,60,70) CKSRYB104K50 C 5337 (A,61,75) CKSQYB105K16 C 5339 (A,65,70) CKSQYB105K16 C 5340 (A,69,72) CKSRYB562K50 C 5341 (A,69,69) CKSRYB152K50 C 5343 (A,62,82) CKSRYB473K25 C 5344 (A,65,83) CFHXSQ221J50 C 5345 (A,71,81) CKSRYB473K25 C 5346 (A,61,77) CKSRYB103K50 C 5347 (A,77,83) 10µF DCH1165 C 5348 (A,75,83) 10µF DCH1165 C 5349 (A,86,72) CKSQYB105K16 C 5350 (A,88,72) CKSQYB105K16 C 5351 (A,120,69) 15pF CCG1194 C 5352 (A,81,72) CKSRYB153K25 C 5353 (A,67,69) CKSRYB104K50 C 5354 (A,84,75) CKSRYB104K50 C 5355 (A,84,78) CKSRYB104K50 C 5356 (A,63,70) CKSRYB474K10 C 5357 (A,59,68) CKSRYF104Z50 C 5371 (A,66,65) CKSRYF104Z50 C 5372 (A,69,65) CKSRYF104Z50 C 5601 (A,105,40) CSZSR330M10 C 5602 (A,93,43) CKSRYB104K50 C 5603 (A,77,44) CKSRYB104K50 C 5604 (A,83,44) CKSRYB105K6R3 C 5605 (A,88,43) CKSRYB104K50 C 5614 (A,124,43) CKSRYB222K50 C 5615 (A,114,45) CKSRYB222K50 C 5616 (A,116,46) CKSRYB222K50 C 5617 (A,114,49) CKSRYB222K50 C 5618 (A,115,50) CKSRYB222K50 C 5619 (A,122,53) CKSRYB223K50 C 5621 (A,13,27) CCSRCH102J50 C 5622 (A,13,26) CCSRCH102J50 C 5623 (A,9,20) CCSRCH102J50 Circuit Symbol and No. Part No. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 160 1 2 3 4 1 2 3 4 C D F A B E C 5624 (A,8,24) CCSRCH102J50 C 5625 (A,103,64) CKSRYB222K50 C 5626 (A,11,54) CKSRYB222K50 C 5627 (A,100,61) CKSRYB222K50 C 5628 (A,102,61) CKSRYB222K50 C 5651 (A,73,60) CKSRYB104K50 C 5670 (A,77,8) CKSRYF104Z50 C 5685 (A,75,15) CCSRCH102J50 C 5686 (A,74,15) CCSRCH102J50 C 5687 (A,69,6) CKSRYB105K6R3 C 5700 (A,86,96) CKSRYB105K6R3 C 5701 (A,70,167) CKSRYB104K50 C 5702 (A,64,11) CKSRYB104K50 C 5703 (A,87,87) CKSRYB104K50 C 5704 (A,87,148) CKSQYB475K6R3 C 5705 (A,85,158) CKSSYF104Z16 C 5801 (A,21,27) CSZSR4R7M25 C 5802 (A,20,23) CKSRYB104K50 C 5803 (A,25,27) CSZS100M10 C 5804 (A,23,23) CKSRYB104K50 C 5805 (A,28,27) CSZSR330M10 C 5806 (A,27,24) CKSRYB104K50 C 5807 (A,31,27) CSZSR33M35 C 5808 (A,30,24) CKSRYB473K25 C 5809 (A,21,32) CKSSYF104Z16 C 5810 (A,25,32) CKSSYF104Z16 C 5819 (A,123,17) CKSRYB104K50 C 5820 (A,125,21) CCSRCH101J50 C 5821 (A,125,19) CKSRYB103K50 C 5822 (A,131,32) CKSRYB104K50 C 5823 (A,122,30) CKSRYB393K16 C 5824 (A,116,31) CKSRYB102K50 C 5825 (A,125,31) CKSRYB105K6R3 C 5828 (A,115,17) CKSRYB104K50 C 5829 (A,118,17) CKSRYB102K50 C 5830 (A,119,17) CKSRYB105K6R3 C 5831 (A,28,32) CKSSYF104Z16 C 5832 (A,32,32) CKSRYB473K25 C 5836 (A,139,19) CSZS100M16 C 5841 (A,139,21) CKSRYF105Z10 C 5842 (A,136,20) CKSRYB104K50 C 5843 (A,140,31) CSZS100M10 C 5844 (A,140,32) CKSRYB104K50 C 5845 (A,140,29) CKSRYB104K50 C 5852 (A,101,6) 33µF/10V CCH1586 C 5854 (A,99,6) CKSRYB104K50 C 5860 (A,116,10) CKSRYB103K50 C 5861 (A,128,6) CKSRYB104K50 C 5862 (A,116,7) 10µF DCH1165 C 5863 (A,112,7) 10µF DCH1165 C 5864 (A,109,7) 10µF DCH1165 C 5865 (A,111,13) CKSRYB103K50 C 5866 (A,128,28) CKSRYB104K50 C 5867 (A,112,18) CKSRYB105K6R3 C 5868 (A,112,19) CKSRYB103K50 C 5869 (A,108,17) CKSRYB472K50 C 5870 (A,108,19) CKSRYB472K50 C 5873 (A,112,30) CKSSYF104Z16 C 5875 (A,102,19) CKSRYB104K50 C 5876 (A,102,17) CKSQYF105Z25 Circuit Symbol and No. Part No. C 5877 (A,102,20) CKSQYF105Z25 C 5881 (A,96,7) CKSQYF105Z25 C 5882 (A,96,19) CKSQYF105Z25 C 5883 (A,129,37) CKSQYF105Z25 C 5884 (A,109,28) CKSRYB103K50 C 5885 (A,125,6) 68µF/6.3V CCH1440 C 5886 (A,107,26) CKSYF475Z16 C 5887 (A,114,33) CKSRYF474Z16 C 5888 (A,118,33) CKSRYF474Z16 C 5889 (A,121,33) CKSRYF474Z16 C 5890 (A,116,37) CKSQYF105Z25 C 5891 (A,119,37) CKSQYF105Z25 C 5892 (A,121,37) CKSQYF225Z16 C 5893 (A,123,37) CKSQYF225Z16 C 5894 (A,133,28) CKSQYF105Z25 C 5895 (A,125,27) CKSRYB393K16 C 5896 (A,129,30) CSZS100M16 C 5897 (A,130,23) CKSRYB473K25 C 5898 (A,128,20) CCSRCH331J50 C 5899 (A,128,25) CKSRYB103K50 C 5900 (A,125,23) CKSRYB393K16 C 5901 (A,40,82) CKSRYB104K50 C 5902 (A,37,75) CSZSR330M10 C 5903 (A,34,76) CFHXSQ562J16 C 5904 (A,45,77) CSZSR330M10 C 5905 (A,36,83) CCSRCH102J50 K Unit Number:CWM9921 Unit Name:Connector Unit MISCELLANEOUS D 2801 (A,25,25) Diode UDZS5R6(B) D 2802 (B,24,26) Diode UDZS5R6(B) D 2803 (A,25,20) Diode HZU12(B2) D 2804 (A,25,23) Diode HZU12(B2) D 2805 (A,38,28) Diode UMZ6R8N D 2806 (A,25,32) Diode UMZ6R8N D 2807 (A,48,14) Diode UMZ6R8N D 2809 (A,48,10) Diode UMZ6R8N D 2811 (A,53,10) Diode UMZ6R8N D 2812 (A,53,14) Diode UMZ6R8N D 2813 (B,44,23) Diode UDZS5R6(B) D 2814 (B,44,29) Diode UDZS5R6(B) L 2801 (A,36,8) Inductor CTF1334 L 2802 (A,34,8) Inductor CTF1334 L 2803 (A,33,8) Inductor CTF1334 L 2804 (A,31,8) Inductor CTF1334 >FU2802 (A,21,7) Fuse 4A CEK1260 EF2801 (A,25,30) EMI Filter CCG1067 RESISTORS R 2801 (A,31,26) RS1/16S102J R 2802 (A,33,26) RS1/16S102J R 2803 (A,31,22) RS1/16S0R0J R 2804 (A,33,22) RS1/16S102J R 2811 (A,38,24) RS1/10S0R0J R 2812 (A,38,21) RS1/10S0R0J R 2813 (A,43,10) RS1/16S102J Circuit Symbol and No. Part No. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 161 5 6 7 8 5 6 7 8 C D F A B E R 2814 (A,22,19) RS1/16S0R0J CAPACITORS C 2801 (A,19,19) CKSRYB102K50 C 2802 (A,20,19) CKSRYB102K50 C 2804 (A,17,19) CKSRYB102K50 C 2809 (A,55,6) CCSRCH101J50 C 2810 (A,50,6) CKSQYF104Z50 L Unit Number:CZW3097 Unit Name:Main PCB Unit MISCELLANEOUS IC 1 IC BA6288FS IC 2 IC S-812C50AMC-C3E IC 3 IC TC7W14FU IC 4 Photo-interrupter GP2L24B IC 5 Photo-interrupter GP2L24B Q 1 Transistor 2SB1185 Q 2 Transistor IMX1 D 1 Diode HZU6R2(B2) L 2 Inductor LCTAW2R2J2520 FU1 Fuse 2A CEK1304 RESISTORS R 1 RS1/16S223J R 2 RS1/8S271J R 3 RS1/16S332J R 4 RS1/16S471J R 5 RS1/16S222J R 11 RS1/10S0R0J R 12 RS1/16S222J R 13 RS1/16S222J R 14 RS1/16S821J R 15 RS1/16S821J R 19 RS1/16S102J R 20 RS1/16S102J R 21 RS1/16S102J R 22 RS1/16S102J CAPACITORS C 1 CKSRYB153K50 C 2 CZC5169 C 3 CKSRYB105K10 C 7 CEVW100M16 C 8 CKSRYB104K50 C 9 CKSRYB473K50 C 10 CKSRYB473K50 C 11 CEVW100M16 C 12 CEVW100M16 C 13 CKSRYB104K50 C 14 CKSRYB104K50 C Unit Number:CWX3178 Unit Name:DVD Core Unit (MS3R) Circuit Symbol and No. Part No. MISCELLANEOUS IC 401 (A,16,29) IC PE5430A IC 402 (A,4,39) IC S-80827CNNB-B8M IC 404 (A,4,36) IC TC7S08F IC 601 (B,11,18) IC BA033FP IC 602 (B,10,71) IC BA18BC0FP IC 1101 (A,15,82) IC AN8703FH IC 1201 (A,46,39) IC BA5985FM IC 1202 (A,45,56) IC BA6859AFP-Y IC 1301 (A,16,56) IC MNZS26EDCUB Q 1101 (B,36,104) Transistor 2SB1260 Q 1102 (B,36,98) Transistor 2SB1260 Q 1103 (B,25,105) Transistor UN2211 Q 1104 (A,24,105) Transistor 2SB709A Q 1105 (A,27,105) Transistor 2SD601A D 1101 (B,33,104) Diode 1SS355 D 1102 (B,33,96) Diode 1SS355 D 1301 (B,25,55) Diode UDZ2R7(B) D 1302 (B,9,81) Chip LED CL205IRXTU L 401 (A,9,17) Inductor CTF1395 L 402 (A,4,33) Inductor CTF1410 L 1301 (B,15,55) Inductor CTF1409 L 1302 (B,8,40) Inductor CTF1409 L 1303 (B,15,58) Inductor CTF1395 L 1305 (B,6,70) Inductor CTF1409 X 401 (A,4,29) Ceramic Resonator 16.000MHz CSS1576 X 1301 (A,33,64) Ceramic Resonator 16.934MHz CSS1603 RESISTORS R 401 (A,28,23) RS1/16SS104J R 403 (A,41,26) RS1/16SS473J R 404 (B,6,36) RS1/16SS473J R 405 (B,6,38) RS1/16SS105J R 406 (B,11,31) RS1/16SS103J R 407 (A,2,20) RS1/16SS104J R 410 (A,26,39) RS1/16SS473J R 414 (A,27,27) RS1/16SS473J R 415 (A,19,15) RS1/16S1002D R 418 (A,32,23) RS1/16SS473J R 419 (A,28,24) RS1/16SS221J R 420 (A,29,27) RS1/16SS103J R 421 (A,29,28) RS1/16SS103J R 423 (A,29,30) RS1/16SS103J R 424 (A,26,32) RS1/16SS221J R 427 (A,29,25) RS1/16SS103J R 433 (B,7,63) RS1/16SS473J R 434 (A,27,22) RS1/16SS223J R 435 (A,26,23) RS1/16SS222J R 436 (A,33,30) RS1/16SS101J R 437 (A,33,31) RS1/16SS101J R 601 (B,7,64) RS1/16SS102J R 603 (A,4,19) RS1/16SS820J R 604 (A,8,10) RS1/16SS820J R 605 (A,9,10) RS1/16SS820J R 606 (A,10,10) RS1/16SS220J R 607 (A,11,10) RS1/16SS103J R 608 (A,19,11) RS1/16SS101J R 612 (B,9,10) RAB4CQ820J Circuit Symbol and No. Part No. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 162 1 2 3 4 1 2 3 4 C D F A B E R 615 (B,11,10) RAB4CQ220J R 616 (B,19,11) RAB4CQ220J R 617 (B,21,14) RAB4CQ220J R 618 (B,24,11) RAB4CQ220J R 620 (A,14,11) RS1/16SS103J R 625 (A,5,19) RS1/16SS220J R 626 (A,4,22) RS1/16SS820J R 627 (A,7,19) RS1/16SS220J R 629 (B,7,13) RS1/16SS103J R 1101 (A,24,97) RS1/16SS101J R 1102 (B,40,101) RS1/16SS3R9J R 1103 (B,42,101) RS1/16SS3R9J R 1104 (B,42,102) RS1/16SS3R9J R 1105 (B,40,102) RS1/16SS3R9J R 1106 (A,21,97) RS1/16SS330J R 1107 (B,40,97) RS1/16SS3R9J R 1108 (B,40,98) RS1/16SS3R9J R 1109 (B,40,99) RS1/16SS3R9J R 1110 (B,40,100) RS1/16SS3R9J R 1111 (B,17,104) RS1/16SS272J R 1112 (B,18,104) RS1/16SS472J R 1113 (B,23,103) RS1/16SS102J R 1124 (A,5,85) RS1/16SS273J R 1125 (A,5,84) RS1/16SS273J R 1126 (A,6,81) RS1/16SS224J R 1133 (A,6,79) RS1/16S2402D R 1134 (A,6,77) RS1/16S1002D R 1135 (A,2,77) RS1/16S2702D R 1140 (A,23,83) RS1/16SS105J R 1141 (A,25,85) RS1/16SS105J R 1142 (B,17,80) RS1/16SS105J R 1151 (B,17,93) RS1/16SS103J R 1152 (B,13,90) RS1/16SS103J R 1201 (A,41,49) RS1/16SS221J R 1202 (A,38,45) RS1/16SS393J R 1203 (A,39,45) RS1/16SS303J R 1205 (B,44,43) RS1/16SS0R0J R 1206 (B,46,44) RS1/16SS102J R 1209 (B,46,38) RS1/16SS221J R 1210 (B,50,42) RS1/16SS393J R 1211 (B,51,44) RS1/16SS393J R 1212 (B,50,45) RS1/16SS393J R 1213 (A,53,47) RS1/16SS393J R 1214 (B,44,47) RS1/16SS221J R 1219 (A,51,50) RS1/16SS221J R 1220 (B,46,39) RS1/16SS221J R 1221 (A,51,60) RS1/16S1802D R 1222 (A,27,79) RS1/16SS221J R 1223 (A,47,64) RS1/16SS2R2J R 1224 (A,48,64) RS1/16SS2R2J R 1228 (A,49,64) RS1/16SS2R2J R 1231 (B,15,7) RS1/16SS822J R 1232 (B,14,7) RS1/16SS822J R 1233 (B,13,8) RS1/16SS822J R 1234 (B,15,10) RS1/16SS563J R 1235 (B,14,10) RS1/16SS243J R 1236 (B,13,10) RS1/16SS683J R 1238 (A,50,64) RS1/16SS2R2J R 1239 (A,51,64) RS1/16SS2R2J R 1241 (A,15,11) RS1/16SS822J Circuit Symbol and No. Part No. R 1242 (B,17,8) RS1/16SS243J R 1243 (B,12,84) RS1/16S391J R 1244 (B,9,84) RS1/16S471J R 1245 (B,19,97) RS1/16SS105J R 1301 (B,18,55) RS1/16SS222J R 1323 (B,21,47) RS1/16SS221J R 1324 (B,22,47) RS1/16SS221J R 1334 (A,34,45) RS1/16SS221J R 1338 (B,26,57) RS1/16SS472J R 1339 (A,32,56) RS1/16SS273J R 1340 (B,26,58) RS1/16SS472J R 1341 (A,32,57) RS1/16SS273J R 1342 (A,34,57) RS1/16SS273J R 1344 (A,32,58) RS1/16SS273J R 1349 (B,27,64) RS1/16SS562J R 1350 (B,27,63) RS1/16SS242J R 1352 (B,24,64) RS1/16S2702D R 1353 (A,28,72) RS1/16SS102J R 1360 (B,21,65) RS1/16SS153J R 1361 (B,18,65) RS1/16SS105J R 1362 (A,7,75) RS1/16SS473J R 1363 (A,3,75) RS1/16SS101J R 1364 (A,7,74) RS1/16SS123J R 1365 (A,4,74) RS1/16SS101J R 1367 (B,13,79) RS1/16SS473J R 1369 (B,15,76) RS1/16SS473J R 1377 (A,2,68) RS1/16SS103J R 1378 (A,1,68) RS1/16SS103J R 1379 (A,1,44) RS1/16SS0R0J R 1380 (A,31,65) RS1/16SS681J R 1381 (A,31,63) RS1/16SS105J R 1383 (B,24,52) RS1/16SS0R0J R 1384 (A,3,68) RS1/16SS103J R 1385 (A,-2,63) RS1/16SS103J R 1386 (A,-1,63) RS1/16SS103J CAPACITORS C 401 (A,20,39) CKSRYB474K10 C 402 (B,6,39) CKSSYB104K10 C 403 (B,6,41) CKSSYB103K16 C 404 (A,4,32) CKSRYB105K10 C 405 (A,11,17) CKSRYB474K10 C 406 (A,19,19) CKSRYB474K10 C 407 (A,16,14) CKSSYB103K16 C 408 (A,19,16) CKSRYB474K10 C 410 (B,6,37) CKSSYB103K16 C 411 (B,6,35) CKSSYB104K10 C 601 (B,8,27) 10µF/10V CCH1349 C 602 (B,12,27) 10µF/10V CCH1349 C 603 (B,14,27) CKSSYB102K50 C 604 (B,6,27) CKSRYB474K10 C 605 (B,11,63) CSZSR470M6R3 C 606 (B,7,65) CKSSYB102K50 C 607 (B,5,78) CKSRYB474K10 C 611 (A,15,13) CCSSCH181J25 C 1101 (B,14,101) CSZSC470M16 C 1102 (A,25,100) CSZSR470M6R3 C 1103 (B,30,105) CKSSYB104K10 C 1104 (B,33,102) CKSSYB103K16 Circuit Symbol and No. Part No. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 163 5 6 7 8 5 6 7 8 C D F A B E C 1105 (A,22,100) CSZSR101M6R3 C 1106 (B,32,100) CKSSYB104K10 C 1107 (B,31,95) CKSSYB103K16 C 1108 (B,23,105) CKSSYB104K10 C 1109 (A,21,105) CKSRYB473K25 C 1110 (A,30,106) CKSRYB473K25 C 1111 (A,32,103) CKSSYB103K16 C 1112 (A,22,94) CKSRYB105K10 C 1113 (A,24,94) CKSRYB105K10 C 1114 (A,31,102) CKSSYB103K16 C 1121 (A,6,83) CKSSYB221K50 C 1122 (A,2,79) CKSRYB393K16 C 1124 (A,13,74) CKSSYB221K50 C 1125 (B,16,76) CKSSYB104K10 C 1126 (A,15,75) CKSSYB104K10 C 1127 (B,17,76) CKSSYB104K10 C 1128 (B,15,80) CKSRYB472K50 C 1129 (A,22,79) CKSSYB104K10 C 1132 (A,25,83) CKSRYB561K50 C 1133 (A,24,86) CKSRYB561K50 C 1134 (A,23,86) CKSRYB273K16 C 1135 (B,20,81) CKSSYB473K10 C 1136 (A,22,90) CKSSYB104K10 C 1137 (A,22,89) CKSSYB104K10 C 1138 (A,14,89) CKSSYB104K10 C 1139 (A,16,90) CKSSYB104K10 C 1201 (A,39,47) CKSSYB104K10 C 1204 (B,1,72) CEVW101M16 C 1205 (A,39,36) CKSRYB104K16 C 1206 (B,45,35) CKSRYB103K50 C 1207 (B,45,34) CKSRYB103K50 C 1208 (B,51,42) CCSSCH5R0C50 C 1209 (B,51,45) CCSSCH470J50 C 1210 (A,51,52) CKSSYB104K10 C 1301 (A,6,42) CKSSYB104K10 C 1302 (A,13,41) CKSSYB104K10 C 1303 (A,15,41) CKSRYB224K10 C 1304 (A,20,42) CKSSYB104K10 C 1305 (A,23,41) CKSRYB224K10 C 1306 (A,32,45) CKSSYB471K50 C 1307 (A,33,52) CKSSYB104K10 C 1308 (A,31,52) CKSRYB224K10 C 1309 (A,35,54) CKSSYB104K10 C 1310 (A,35,55) CKSSYB104K10 C 1311 (A,35,57) CKSSYB103K16 C 1312 (A,37,58) CKSSYB103K16 C 1313 (A,30,61) CKSSYB104K10 C 1314 (A,34,61) CKSRYB224K10 C 1315 (B,27,65) CKSRYB102K50 C 1316 (B,24,65) CKSRYB393K16 C 1317 (A,30,68) CKSSYB104K10 C 1318 (A,30,71) CKSSYB103K16 C 1319 (A,27,77) CKSSYB104K10 C 1320 (A,24,78) CKSSYB103K16 C 1329 (A,22,72) CKSSYB104K10 C 1330 (B,24,67) CKSRYB183K50 C 1331 (B,21,66) CCSSCH470J50 C 1332 (A,20,72) CKSRYB224K10 C 1333 (A,19,72) CKSRYB105K10 C 1334 (B,15,67) CKSRYB102K50 Circuit Symbol and No. Part No. C 1335 (B,18,63) CKSSYB562K25 C 1336 (A,18,72) CKSSYB104K10 C 1337 (A,16,72) CKSRYB102K50 C 1338 (B,16,69) CKSRYB102K50 C 1339 (A,15,72) CKSRYB102K50 C 1340 (A,13,71) CKSSYB104K10 C 1341 (B,16,66) CCSSCH101J50 C 1342 (B,16,65) CKSRYB391K50 C 1343 (B,16,63) CKSRYB471K50 C 1344 (B,16,62) CKSRYB331K50 C 1346 (A,8,71) CKSRYB224K10 C 1347 (A,1,61) CKSSYB104K10 C 1348 (A,1,57) CKSSYB104K10 C 1349 (A,2,56) CKSSYB104K10 C 1350 (A,2,52) CKSSYB104K10 C 1351 (A,1,48) CKSSYB104K10 C 1352 (A,1,46) CKSSYB104K10 C 1355 (B,2,59) CSZS100M6R3 D Unit Number:CWX3154 Unit Name:Compound Unit(A) Q 1299 Photo-taransistor CPT231SCTD S 1201 Spring Switch(12cm) CSN1069 S 1202 Spring Switch(8cm) CSN1069 S 1203 Spring Switch(DISC SENS) CSN1069 S 1204 Spring Switch(DISC SENS) CSN1070 S 1205 Spring Switch(8cm) CSN1070 R 1298 RS1/16S0R0J R 1299 RS1/16S0R0J E Unit Number:CWX3156 Unit Name:Compound Unit(B) S 1206 Switch(CLAMP) CSN1051 F Unit Number:CWX3096 Unit Name:CD Core Unit(S10.1) MISCELLANEOUS IC 201 (A,39,24) IC UPD63763GJ IC 203 (B,45,78) IC NJM2885DL1-33 IC 301 (A,49,88) IC BA5835FP IC 701 (A,48,51) IC PE5454B IC 703 (A,30,44) IC S-812C33AUA-C2N Q 101 (A,20,22) Transistor 2SA1577 Q 701 (B,62,59) Transistor UN2111 L 203 (A,53,32) Inductor CTF1389 L 207 (A,53,31) Inductor CTF1389 L 209 (A,26,20) Inductor CTF1389 L 703 (A,64,49) Inductor CTF1389 X 201 (A,51,35) Ceramic Resonator 16.934MHz CSS1603 X 701 (A,59,53) Ceramic Resonator 4.00MHz CSS1652 S 901 (A,15,43) Switch(HOME) CSN1067 S 903 (B,53,100) Switch(DSCSNS) CSN1068 Circuit Symbol and No. Part No. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 164 1 2 3 4 1 2 3 4 C D F A B E S 904 (B,35,108) Switch(12EJ) CSN1067 S 905 (B,48,109) Switch(8EJ) CSN1067 RESISTORS R 101 (A,22,24) RS1/10SR2R4J R 102 (A,22,26) RS1/10SR2R4J R 103 (A,25,25) RS1/10SR2R7J R 201 (A,53,16) RS1/16SS102J R 202 (A,55,21) RS1/16SS333J R 221 (B,31,18) RS1/16SS103J R 222 (B,26,18) RS1/16SS103J R 225 (A,27,8) RS1/16SS103J R 226 (A,27,7) RS1/16SS393J R 227 (B,33,10) RS1/16SS562J R 228 (B,36,8) RS1/16SS122J R 229 (B,34,8) RS1/16SS472J R 232 (B,35,10) RS1/16SS122J R 241 (B,42,28) RS1/16SS333J R 243 (B,44,28) RS1/16SS333J R 245 (A,39,38) RS1/16SS333J R 301 (A,48,78) RS1/16SS183J R 302 (A,42,78) RS1/16SS822J R 304 (A,50,78) RS1/16SS183J R 305 (A,42,77) RS1/16SS822J R 307 (A,36,85) RS1/16SS183J R 308 (A,32,83) RS1/16SS183J R 309 (A,38,89) RS1/16SS183J R 310 (A,35,88) RS1/16SS183J R 601 (B,43,59) RS1/16S101J R 602 (B,41,62) RS1/16S101J R 606 (B,44,67) RS1/16S0R0J R 607 (B,43,56) RS1/16SS0R0J R 608 (B,36,67) RS1/16SS0R0J R 705 (B,50,59) RS1/16SS221J R 706 (B,57,61) RS1/16SS221J R 707 (A,62,47) RS1/16SS473J R 708 (B,50,57) RS1/16SS221J R 710 (A,28,77) RS1/16SS102J R 711 (B,44,53) RS1/16SS221J R 714 (B,51,53) RS1/16SS473J R 716 (A,63,56) RS1/16SS472J R 719 (B,49,45) RS1/16SS221J R 720 (B,46,52) RS1/16SS471J R 724 (A,62,42) RS1/16S473J R 725 (B,57,43) RS1/16SS222J R 726 (A,52,41) RS1/16SS103J R 727 (B,50,54) RS1/16SS473J R 729 (A,57,40) RS1/16SS223J R 730 (A,65,41) RS1/16SS473J R 731 (A,53,41) RS1/16SS104J R 737 (A,41,42) RS1/16SS104J R 740 (A,35,46) RS1/16SS473J R 742 (A,50,41) RS1/16SS104J R 746 (B,60,56) RS1/16SS104J R 750 (A,39,59) RS1/16SS473J R 754 (B,48,60) RS1/16SS102J R 755 (A,43,61) RS1/16SS102J R 765 (B,51,40) RAB4CQ221J R 769 (B,48,40) RAB4CQ221J Circuit Symbol and No. Part No. R 773 (B,39,37) RAB4CQ221J R 777 (B,48,51) RS1/16SS221J R 778 (B,48,52) RS1/16SS221J R 779 (B,45,54) RS1/16SS221J R 901 (B,52,65) RAB4CQ221J R 905 (B,54,60) RS1/16SS221J R 906 (B,56,68) RS1/16SS221J R 908 (B,45,69) RS1/16SS0R0J R 910 (B,44,69) RS1/16SS0R0J R 911 (B,40,73) RS1/16SS102J CAPACITORS C 103 (B,14,8) 100µF/16V CCH1504 C 105 (A,19,15) CKSSYB104K10 C 108 (B,39,16) CKSSYB104K10 C 110 (A,18,6) CKSSYB104K10 C 201 (A,51,14) CKSSYB102K50 C 202 (B,50,17) CKSSYB104K10 C 203 (A,55,23) CKSSYB104K10 C 204 (B,28,22) CEVW220M6R3 C 205 (A,53,25) CKSSYB104K10 C 208 (B,44,25) CKSSYB104K10 C 209 (A,54,29) CKSSYB104K10 C 212 (A,45,37) CKSRYB105K10 C 216 (A,25,8) CKSSYB332K50 C 217 (A,28,12) CKSSYB104K10 C 218 (A,25,7) CKSSYB473K10 C 219 (A,34,7) CKSSYB104K10 C 220 (A,33,11) CKSSYB182K50 C 221 (B,35,6) CKSSYB104K10 C 222 (B,35,8) CCSSCH560J50 C 223 (B,33,8) CCSSCH4R0C50 C 224 (B,40,16) CKSSYB104K10 C 225 (B,45,14) CKSSYB103K16 C 226 (B,43,12) CCSSCH680J50 C 227 (A,45,10) CCSSCH470J50 C 228 (A,49,9) CKSSYB103K16 C 234 (B,36,81) CEVW221M4 C 237 (B,38,29) CKSSYB104K10 C 239 (B,34,10) CCSSCH220J50 C 242 (B,58,32) CKSSYB104K10 C 243 (B,39,76) CKSSYB104K10 C 244 (B,49,70) CKSSYB104K10 C 246 (A,23,19) CKSSYB104K10 C 251 (B,28,31) CKSRYB102K50 C 260 (A,54,25) CKSSYB104K10 C 301 (A,43,78) CKSSYB221K50 C 302 (A,50,79) CKSSYB221K50 C 303 (A,37,85) CKSSYB472K25 C 304 (A,39,89) CKSSYB103K16 C 305 (B,34,92) CEVW101M16 C 307 (B,56,90) CKSSYB104K10 C 601 (B,46,60) CCSRCH102J50 C 602 (B,41,65) CCSRCH102J50 C 701 (A,64,46) CKSSYB104K10 C 703 (B,50,61) CKSSYB103K16 C 706 (B,50,62) CKSSYB104K10 C 707 (A,36,45) CKSSYB104K10 C 712 (A,22,42) CKSRYB224K16 C 714 (B,60,45) CKSSYB104K10 Circuit Symbol and No. Part No. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 165 5 6 7 8 5 6 7 8 C D F A B E C 716 (A,61,40) CKSSYB103K16 C 722 (B,52,48) CKSQYB475K6R3 C 723 (A,26,41) CKSRYB105K10 C 903 (B,56,70) CKSSYB471K50 C 906 (A,40,77) CKSRYB224K16 C 907 (A,47,76) CKSSYB103K16 C 910 (B,60,71) CKSQYB225K10 Miscellaneous Parts List Pickup Unit(Service) CXX1815 M 1 Motor Unit(LOADING) CXC4659 M 2 Motor Unit(CARRIAGE) CXC4314 M 3 Motor(SPINDLE) CXM1308 Pickup Unit(P10)(Service) CXX1641 M 1 Motor Unit(SPINDLE) CXC4440 M 2 Motor Unit(LOADING/CARRIAGE) CXB8933 M 10 Motor Unit(FLAP) CZX5102 LCD Panel CWX3229 Fan Motor CXM1320 Circuit Symbol and No. Part No. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 166 1 2 3 4 1 2 3 4 C D F A B E 6. ADJUSTMENT 6.1 JIG CONNECTION DIAGRAM - Jigs List Name 45-Pin FFC 23-Pin BBR FFC 80-Pin FFC 20-Pin Extension Cord 30-Pin FFC 33-Pin FFC Monitor Adjustment PCB Test Disc Test Disc L.P.F. Test Disc Jig No. GGD1321 GGD1307 GGD1406 GGD1327 GGD1171 GGD1262 GGF1416 GGV1237 TCD-782 GGV1018 Remarks DVD Mechanism Module(MS3)(CN601) <--> CC Unit(CN2) ( )( ) ( ) CD Mechanism Module(S10.1)(CN901) <--> System Unit(CN1301) System Unit(CN1701) <--> CC Unit(CN605) System Unit(CN1802) <--> CC Unit(CN801) CC Unit(CN702) <--> Connector Unit(CN2804) CC Unit(CN701) <--> Monitor PCB(CN5002) For OSD display (*1) Operation check Checking the grating(CD) Checking the grating(Two pieces) Checking the grating(DVD) ( )( ) y ( ) y ( ) ( ) y ( ) ( ) ( ) ( ) y ( ) g g g( ) g g g *1) Since this product does not have OSD IC, OSD for adjustment is displayed by using GGF1416 at the time of monitor adjustment. S10.1AAC www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 167 5 6 7 8 5 6 7 8 C D F A B E 6.2 DVD ADJUSTMENT 1) Precautions This product uses 5V and 3.3V as standard voltages. The electrical potential that is the reference for signals, is not GND, but VREF 2.2V) and VHALF . During product adjustments, if the reference voltage is mistakenly taken as GND, a grounding contact is made, not only it to measure the accurate also the would r in the of a strong impact on the pick up. The following precaution- ary measures should be strictly adhered to, in order to The reference voltage and should not be confused when using the minus probe of a device. When an is being used special care should be sure the reference is not to the of ch1 (on the minus side), to GND. Further, since the body frame of most mea- surement have the same as - surement device should be set to floating ground. If the r voltage is to GND by mis- take, the regulator OFF i , or turn the F. • Remove the filters and wires used for measurements . • After the power supply is turned on, ON the adjustment and measurement are promptly done. • e will not take any protective For reason, special be to m no mechanical or shock could be applied to the product when taking measurements in the test mode. • the EJECT key is pressed to eject the disk, no other , be pressed until the disk eject action has complet- ed. • Press the EJECT key only after the disk has stopped . • If the product hangs up turn the power OFF immedi- ately. • Laser didoes may be damaged, if the volume switch for Attention) • Test mode starting procedure Please select "MS3 check" to start test mode. • Test mode stopping procedure ACC and Backup OFF. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 168 1 2 3 4 1 2 3 4 C D F A B E Test mode In Test mode In T Set source to DVD Start test mode FE test mode Power On Power Off CRG + CRG – LD_ON Focus close adjustment Focus Search Power Off CRG + CRG – T.Bal and other adjustments Focus Jump Power Off Focus Jump ID Search Tracking Open T. Jump +/– ID specification Track number specification Error Rate measurement (Note 2) Reproduction speed switching (Note 3) Power Off CRG – Tracking close adjustment CRG + Disc Type (Note 1) Eject EDC1 mode EDC2 mode Focus Search Stop CRG_HOME LEFT Power off condition Power on condition Focus close condition 2 Focus close condition 1 Tracking close condition ID Search Start Jump start 0X00 0000 0FFF 0000 0FFF 0000 1X00 0000 2X00 0000 1FFF 0000 0000 0000 1A00 0000 1100 0000 TEST FE offset coefficient TE offset coefficient AS offset coefficient ENV offset coefficient TG offset coefficient DBALt coefficient FE MAX level FE MIN level AS MAX level ENV MAX level FE normalization feature Spindle gain coefficient TEMAX level TEMIN level TBAL Coefficient(Layer 0) TBAL Coefficient(Layer 1) TE normalization feature (Layer0) TE normalization feature (Layer1) FBAL Coefficient(Layer0) FBAL Coefficient(Layer1) Focus Gain Coefficient(Layer0) Focus Gain Coefficient(Layer1) Tracking Gain Coefficient(Layer0) Tracking Gain Coefficient(Layer1) AS normalization adjustment feature (Layer0) AS normalization adjustment feature (Layer1) 2FFF 0000 Layer L0:2000 0000 Layer L1:2100 0000 Layer L0:4X00 0000 Layer L1:4X00 0000 3000 0000 3FFF 0000 3B00 0000 DVD x 1.3 ~ 1.6CAV CD x 4CLV: 4X00 0000 3C00 0000 4A00 0000 Jump+: 4B00 0000 Jump-: 4C00 0000 ID display Track number display 4000 0000 4X00 0000 Error Rate Focus Gain Coefficient(Layer0) Focus Gain Coefficient(Layer1) Tracking Gain Coefficient(Layer0) Tracking Gain Coefficient(Layer1) AS normalization adjustment feature (Layer0) AS normalization adjustment feature (Layer1) Operation while key is being pushed. Operation while key is being pushed. Operation while key is being pushed. Operation while key is being pushed. 2B00 0000 2C00 0000 Note 1: At this stage select the media type. Various settings are carried out Note 2: While measurements are being taken, only the operation, for which Note 3: Reproduction (play) speed is selectable from Note 4: Gain change: Normal gain -> OEIC=H -> OEIC=H and FEP x 4 AMP ON DVD : x1.3 1.6CAV,CD : x 4CLV Fixation [1] : DVD, single-layer [2] : DVD, dual-layer [3] : CD-ROM - Front-End test mode flow chart 1B00 0000 1C00 0000 1D00 0000 LD_ON :1100 0000 LD_OFF:1000 0000 [1] [2] [3] [1] [2] [3] [3] [4] [5] [BACK] [BACK] [BACK] [BACK] [2] [2] [1] [1] [2] [2] [2] [1] [2] [3] [4] [5] [4] www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 169 5 6 7 8 5 6 7 8 C D F A B E Layer 0 selected Layer 1 selected EDC1 mode ID designation EDC1 start Layer 0 selected Layer 1 selected EDC2 mode ID designation EDC2 start F-close and F-search cannot be executed, unless LD-ON is set. 0000 0000 0000 0000 0100 0000 1103 0000 Layer0:10** **** Layer1:11** **** ** ****: ID specification value Layer0:20** **** Layer1:21** **** ** ****: Present ID value 0000 0000 1003 0000 0100 0000 1103 0000 0000 0000 1003 0000 Layer0:10** **** Layer1:11** **** ** ****: ID specification value Layer0:20** **** Layer1:21** **** ** ****: Present ID value The track number designation is selected from the track numbers already prepared for selection. Switching to cyclic operation is made at step 1, and the decision is finalized (entered) in step 3. For CD: Tracks 1, 4, 10, 11 and 32. For DVD: Tracks 1, 4, 10, 11, 32, 64 and 100. Method for designating an ID address: • and LEFT. Numerical UP/DOWN operations are performed through commands 1 and 2 3. Error status from DVD microcomputer Contents Display 0X50 Mecha. error No display 0X40 No disc No display 0X30 Thermal Protection in Motion 0X20 Read error Error-02-XX 0XE2 Non-playable disc NON-PLAY AY A ABLE DISC YABLE DISC Y 0X90 Different region disc 0XFF Undefined error Error-FF ) Error Code Contents Display 0X99 Data cannot read Please confirm the disc 0X80 The address cannot be found Please confirm the disc 0X90 Focus error Please confirm the disc 0X91 Spindle lock NG DVD is stopping because mechanism detected abnormality 0X92 Carriage home NG DVD is stopping because mechanism detected abnormality 0X93 FOK error Please confirm the disc 0X94 ID/Subcode cannot be read Please confirm the disc 0X95 High spindle rotation 0X96 Row spindle rotation DVD is stopping because mechanism detected abnormality DVD is stopping because mechanism detected abnormality 0X98 TOC cannot be found Please confirm the disc 0X9A AV chip error DVD is stopping because mechanism detected abnormality 0X9B RecaveryNG(BE) Play state error Disc data error DVD is stopping because mechanism detected abnormality Display Error Code List [If F-close isn't executed within 9 seconds after LD-ON, it switches to LD-OFF automatically. And even if F-search is executed within 9 seconds after LD-ON, it also switches to LD-OFF.] Please carry out F-close after carrying out power-off at once and carrying out power-on again, when carrying out F-close after performing F-search. 0X9C 0X9D 0X9E Serface error (Disc distinction is improper) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 170 1 2 3 4 1 2 3 4 C D F A B E Oscilloscope RFOUT GND1 If any of the following replacements have been performed on the system, adjustments for pick up, must be conducted: 1. Pick up unit replacement 2. Spindle motor replacement 3. Carriage chassis replacement 4. Pick up unit main shaft replacement 5. Pick up unit sub-shaft replacement Measurement device and tools Disk used Measurement reference Measurement point Connection diagram DVD core unit : Oscilloscope Allen key wrench Screw lock (GYL1001) : GGV1018 : GND1 : RFOUT - Skew adjustment The skew adjustment is to adjust the pickup and the flatness of the disc so that the beam from the pickup continues to go to the disc vertically. In MS3 mecha, the pickup shaft on the inner track near the carriage motor is fixed, so the fixed position is regarded as the standard and the flatness is adjusted. Observing the RF waveform on the oscilloscope, repeat the adjustment on the inner track position and the outer track position, and narrow the adjusted value. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 171 5 6 7 8 5 6 7 8 C D F A B E Apply glue Shaft Skew adj. screw Skew adj. screw Prevent applied glue from extending beyond this position. Prevent applied glue from extending beyond this position. B A C 1 Symptoms in case of poor adjustment: Caution: Avoid exposing your eyes to laser beams for a long time. Preparation for adjustment: Clean both ends of the shafts. Use brand new skew screws supplied with the service kit GXX1234. Procedures: 1. Place the DVD mechanism module upside down. To avoid the disc from being robbed when it is turned upside down, first put a coin of about 1.5 mm on the table, then turn the disc upside down and set it so that the 1 in the figure comes to the point immediately above the coin. 2. After replacing the pickup (by referring to the procedures of "Removing the Pickup."), roughly adjust the three skew screws through visual check so that the pickup is mounted in parallel to the CRG chassis around the inner and outer tacks. 3. Connect an oscilloscope as shown in the connecting diagram. 4. Turn on the power of the product. Load the test disc (GGV1018). 5. In the front-end test mode, set the disc type to DVD layer 1. Then, turn on the power. Move the pickup toward the inner tracks. 6. Turn on the laser diodes. 7. With the focus servo closed, complete all automatic adjustments. Close the tracking servo, and then complete all automatic adjustments. 8 Follow the next procedures, from 8-1 to 8-5, and adjust the (three) skew screws. 8-1 Move the pickup toward the inner track and turn the skew adjustment screw C so that the RF level of oscilloscope becomes the maximum. (Tangential adjustment at the inner track position: Adjust the flatness of the disc at the inner track position with the adjustment screw C) 8-2 Move the pickup toward the outer track and turn the skew adjustment screw B so that the RF level becomes the maximum. (Tangential adjustment at the outer track position: Adjust the flatness of the disc at the outer track position with the adjustment screw B) 8-3 Leave the pickup at the outer track position and turn the skew adjustment screws A and B in the same direction alternately one quarter at a time (A•B•A•B •••) so that the RF level becomes the maximum. (Radial adjustment at the outer track position: Keeping the flatness at the outer track position, adjust the flatness of the whole disk with the adjustment screws A and B) 8-4 Move the pickup toward the inner track and turn the skew adjustment screw C so that the RF level becomes the maximum. (Tangential adjustment at the inner track position: Adjust the flatness of the disc at the inner track position with the djustment screw C) 8-5 Repeat the steps from 8-2 to 8-4 three times, and adjust at the position where the RF level becomes the maximum. 9. Turn off the power in the test mode. After confirming that the disc has stopped, eject the disc. 10. Adjust with a screw rock the shaft and skew adjustment screw to the same state as initial one. Error efficiency deteriorated: 10 (Optimum value: 10 or lower) High jitter of the RF signal RF waveform deformed Unstable operation in tracking closing and servo control -3 -4 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 172 1 2 3 4 1 2 3 4 C D F A B E 6.3 CD ADJUSTMENT 1) Cautions on adjustments • In this product the single voltage (3.3V) is used for the regulator. The reference voltage is the REFO1 (1.65V) instead of the GND. If you should mistakenly short the REFO1 with the GND during adjustment, accurate voltage will not be obtained, and the servo’s misoperation will apply excessive shock to the pickup. To avoid such problems: a. Do not mix up the REFO1 with the GND when connecting the (-) probe of measuring instruments. Especially on an oscilloscope, avoid connecting the (-) probe for CH1 to the GND. b. In many cases, measuring instruments have the same potential as that for the (-) probe. Be sure to set the measuring instruments to the floating state. c. If you have mistakenly connected the REFO1 to the GND, turn off the regulator or the power immediately. • Before mounting and removing filters or leads for adjustment, be sure to turn off the regulator. • For stable circuit operation, keep the mechanism operating for about one minute or more after the regulator is turned on. • In the test mode, any software protections will not work. Avoid applying any mechanical or electrical shock to the mechanism during adjustment. • The RFI and RFO signals with a wide frequency range are easy to oscillate. When observing the signals, insert a resistor of 1k ohms in series. • The load and eject operation is not guarantied with the mechanism upside down. If the mechanism is blocked due to mistaken eject operation, reset the product or turn off and on the ACC to restore it. 2) Test mode This mode is used to adjust the CD mechanism module. • To enter the test mode. While pressing the ANGLE and SOURCE keys at the same time, reset. • To exit from the test mode. Turn off the ACC and back up. Notes: a. During ejection, do not press any other keys than the EJECT key until the loaded disc is ejected. b. If you have pressed the (→) key or (←) key during focus search, turn off the power immediately to protect the actuator from damage caused by the lens stuck. c. For the TR jump modes except 100TR, the track jump operation will continue even if the key is released. d. For the CRG move and 100TR jump modes, the tracking loop will be closed at the same time when the key is released. e. When the power is turned off and on, the jump mode is reset to the single TR (91), the RF amp gain is set to 0dB, and the auto-adjustment values are reset to the default settings. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 173 5 6 7 8 5 6 7 8 C D F A B E [BAND] [BAND] [BAND] [BAND] [BAND] Power On (T.Offset is adjusted) TRK00 MIN00 SEC SEC 00 [CD]or[SOURCE] Source On TRK MIN [ANGLE]+[SOURCE]+Reset or [ANGLE]+[SOURCE]+BU+ACC Test Mode In [3] [1] [1] Power On (T.Offset is not adjusted) TRK99 MIN99 SEC99 [2] [2] [2] [2] Power Off TRK MIN SEC Power Off TRK MIN SEC Power Off TRK MIN SEC Power Off TRK MIN SEC Focus Close S curve check T.Close and AGC Applicable servomechanism TRK91 MIN91 SEC91 [6] [1] [3] [6] [3] Focus Mode switching SPINDLE Speed switching RF AMP Gain switching TRK0xMIN0xSEC0x Tracking Servo Close TRK00 MIN00 SEC00 or TRK99 MIN99 SEC99 CRG- TRK00 MIN00 SEC00 or TRK99 MIN99 SEC99 [→] [←] [→] [←] [→] [←] CRG+ TRK00 MIN00 SEC00 or TRK99 MIN99 SEC99 Automatic adjustment switching TRK?? MIN?? SEC?? T.Close Applicable servomechanism TRK?tr MIN?min SEC?sec [6] [3] TRK MIN SEC RF AGC / RF AGC coefficient display TRK?? MIN?? SEC?? CRG+ TRK8x MIN8x SEC8x or TRK9xMIN9xSEC9x CRG- TRK8x MIN8x SEC8x or TRK9xMIN9xSEC9x T.Balance adjustment / T.BAL coefficient display TRK?? MIN?? SEC?? F,T,RF AGC F.Bias display switching TRK?? MIN?? SEC?? F,T AGC / F.Bias RF AGC TRK MIN SEC CRG/TR Jump value switching TRK MIN SEC CRG/TR Jump + TRK MIN SEC CRG/TR Jump - TRK MIN SEC Tracking Open TRK8xMIN8xSEC8x or TRK9xMIN9xSEC9x Tracking Open TRK8x MIN8x SEC8x or TRK9xMIN9xSEC9x TRKSP MINSP SECSP [4] TRKGGMINGGSECGG [2] [Key] [BAND] [→] [6] [1] [2] [3] Power On / Off CRG + / TR Jump + (Direction of the external surface) CRG - / TR Jump - (Direction of the internal surface) U.CLS and AGC and Applicable servomechanism / AGC, AGC display setting RF Gain switching / Offset adjustment display / T.Balance adjustment / T.Open Close, S.Curve / Rough Servo and RF AGC / SPDL 1X / 2X switching As for the double speed (2x), audio output cannot be supported. Error Rate measurement 1st - ON : ERR count Beginning (30Sec) 2nd - ON : BER display data [%] F.Mode switching / Tracking Close / CRG • TR Jump switching Test Mode Operation [KEY] Contents Display F, T, RF AGC *1) TYP → -6dB → -12dB TRK MIN SEC TRK 06 MIN 06 SEC 06 TRK 12 MIN 12 SEC 12 *2) Focus Close → S.Curve check setting → F EQ measurement setting *9) Applicability : A, B, C, D, E, F As for the double speed (2x), audio output cannot be supported TRK 00 MIN 00 SEC 00 TRK 01 MIN 01 SEC 01 TRK 02 MIN 02 SEC 02 (TRK 99 MIN 99 SEC 99) *3) F.Offset Display → T.Offset Display → Switch to the order of the original display *4) 1TR / 32TR / 100TR *5) Single TR → 32TR → 100TR → CRG Move 9x(8x) : 91(81) 92(82) 93(83) 94(84) *6) Only at the time of CRG move, 100TR jump *7) TRK/MIN/SEC → F.AGC → T.AGC → F Bias → RF AGC *8) CRG motor voltage = 2[V] [←] - Flow Chart *1 *9 *2 *8 *8 *3 *7 *5 *4 *4 *6 ?tr ?min ?sec ?tr ?min ?sec ?tr ?min ?sec ?tr ?min ?sec ?tr ?min ?sec TYP(1X) → 2X → 1X TRK MIN SEC TRK 22 MIN 22 SEC 22 TRK 11 MIN 11 SEC 11 Applicability : G TYP(2X) → 1X → 2X TRK MIN SEC TRK 11 MIN 11 SEC 11 TRK 22 MIN 22 SEC 22 [4] [5] www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 174 1 2 3 4 1 2 3 4 C D F A B E 6.4 CHECKING THE GRATING AFTER CHANGING THE PICKUP UNIT • Note : The grating angle of the PU unit cannot be adjusted after the PU unit is changed. The PU unit in the CD mechanism module is adjusted on the production line to match the CD mechanism module and is thus the best adjusted PU unit for the CD mechanism module. Changing the PU unit is thus best considered as a last resort. However, if the PU unit must be changed, the grating should be checked using the procedure below. • Purpose : To check that the grating is within an acceptable range when the PU unit is changed. • Symptoms of Mal-adjustment : If the grating is off by a large amount symptoms such as being unable to close tracking, being unable to perform track search operations, or taking a long time for track searching. • Method : • Measuring Equipment • Measuring Points • Oscilloscope, Two L.P.F. • E, F, REFO1 • Disc • TCD-782 • Mode • TEST MODE • Checking Procedure 1. In test mode, load the disc and switch the 3V regulator on. 2. Using the → and ← buttons, move the PU unit to the innermost track. 3. Press key 3 to close focus, the display should read "91". Press key 2 to implement the tracking balance adjustment the display should now read "81". Press key 3. The display will change, returning to "81" on the fourth press. 4. As shown in the diagram above, monitor the LPF outputs using the oscilloscope and check that the phase difference is within 75° . Refer to the photographs supplied to determine the phase angle. 5. If the phase difference is determined to be greater than 75° try changing the PU unit to see if there is any improvement. If, after trying this a number of times, the grating angle does not become less than 75° then the mechanism should be judged to be at fault. • Note Because of eccentricity in the disc and a slight misalignment of the clamping center the grating waveform may be seen to "wobble" ( the phase difference changes as the disc rotates). The angle specified above indicates the average angle. • Hint Reloading the disc changes the clamp position and may decrease the "wobble". 100kΩ 390pF 100kΩ 390pF E VREF F VREF Xch Ych L.P.F. L.P.F. REFO1 F E CD CORE UNIT(S10.1) Oscilloscope www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 175 5 6 7 8 5 6 7 8 C D F A B E Grating waveform 45° 0° 75° 60° 30° 90° Ech → Xch 20mV/div, AC Fch → Ych 20mV/div, AC www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 176 1 2 3 4 1 2 3 4 C D F A B E 6.5 ERROR MODE - Error Messages Error is displayed with number for Error cause when CD is inoperative or stops with Error during operation. The purpose is to reduce nonsense calls from users as well as to assist all related analysis and repair for defects at service station. (1) Basic Display Method 1) When CSMOD (CD mode area for system) is SERRORM, Error code will be written in DMIN (minutes area for display), DSEC (seconds area for display). The same data shall be written in DMIN and DSEC. DTNO is blank as usual. 2) Display Example of Head Unit The following is about LCD display ability. xx is Error number. 8 digits 6 digits 4 digits ERROR–xx ERR–xx E–xx (2) Error Code List No. Classification Contents Details • Cause 10 Electricity Carriage Home NG CRG can’t move to the inner. CRG can’t move from the inner. → HOME SW failure, CRG movement failure. 11 Electricity Focus Search NG Focus can’t be caught. → Back of Disc / Severe dirt and vibration. 23 Disc File Format NG Contents are stored in an incompatible file format. → The contents in a CD-ROM disc inserted are recorded in a file format other than ISO9660 Level-1 and 2. 22 Disc Impossible to play There is no playable MP3 or WMA file present in a disc. → No MP3 or WMA file exists in a CD-ROM disc inserted. 17 Electricity Setup NG AGC protection doesn’t work, out of Focus soon. → Scratch on Disc/Severe dirt and vibration. 12 Electricity Spindle Lock NG Not spindle, lock. Wrong subcode (can’t read). Subcode NG RF-amp NG → Defective Spindle. Scratch and dirt on Disc. Intense vibration. The appropriate gain of the RF amp cannot be obtained. → Defective spindle. → Blanc CD-R disc. Disc inserted upside down. → Scratched or dirty disc. Severe vibration. Abnormal CD signals. 30 Electricity Search Time Out Can’t reach the target address. → Defective CRG/tracking, or scratch on Disc. → All TRK Nos. In a disc inserted are specified as a track which should be skipped, in the track skip information. 44 Disc Impossible to play There is no playable TRK No. present in a disc. 50 Mecha Disc Load / Eject NG Disc loading/ejection cannot be complete. → Foreign objects entered into the mechanism. Disc caught in between during loading/ejection. A0 System Power NG Power supply (VD) isn’t connected to the ground. → Defective SW transistor. Abnormal power (failed connector) OR Err–xx Note : Error doesn’t display in mechanism only. (CD off causes mechanism off) If TOC can’t be read, error wouldn’t occur, but mechanism still continues its operation. The upper digits of error code is mainly classified by 3 kinds as follows: 1x: Setup related error, 3x: Search related error, Ax: Other errors. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 177 5 6 7 8 5 6 7 8 C D F A B E 6.6 MONITOR PCB ADJUSTMENT FLW2 FLP2 V5 VM12 V25 V33 VFL NVSYNC VVI V18 V8 CSYNCO VB VG VR VCOM ANR ANG ANB INVPUL INVBST GNDFL DIMDTY CN5009 IC5001 CN5007 CN5801 CN5002 IC5601 CN5008 VR5331 T5331 CN5331 - Adjustment point MONITOR PCB(SIDE A) MONITOR PCB(SIDE B) EPRTEST www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 178 1 2 3 4 1 2 3 4 C D F A B E Notes: When the power supply for TC90A64AF-P (IC4001) is OFF, be careful not to apply any voltage to its terminals except for IIC lines(SDA and SCL). The IIC lines can accept a maximum of 5V. No Adjustment item Measuring point 1 2 3 4 5 6 3.3V power supply verification 2.5V power supply verification (TP V33) V33 = 3.3V ± 0.3V V25 = 2.5V ± 0.2V (TP V25) (TP V5) (TP V8) (TP V18) (TP VM12) Input Apply 14.4V to TP VVI. Apply 14.4V to TP VVI. 5V power supply verification V5 = 5.0V ± 0.3V Apply 14.4V to TP VVI. 8V power supply verification V8 = 8.0V ± 0.6V Apply 14.4V to TP VVI. 18.5V power supply verification V18 = 18.5V ± 0.8V Apply 14.4V to TP VVI. -12V power supply verification VM12 = -12.0V ± 0.6V Apply 14.4V to TP VVI. Adjusting point Measuring method and specs. Remarks www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 179 5 6 7 8 5 6 7 8 C D F A B E No Adjustment item Input Vcom amp output Voltage waveform Verification Any input signal 7 Adjusting point Measuring method and specs. Remarks Measuring point TP VCOM Input waveform verification (composite) Apply a white 100% signal toTP CSYNCO. 10 TP CSYNCO The signal generator should be used via 75 ohms. RGB amp output voltage waveform verification Apply a black signal to TP ANR,ANG,ANB. (Video level:0%) 11 12 TP VG The input signal has no setup. (Apply a black signal to TP CSYNCO) Gamma 0 Verification Apply a 10-step signal to TP ANR,ANG,ANB. TP VG The input 10-step signal has no setup. 1.0V ± 0.02V Input waveform verification (RGB) Apply a white 100% signal to TP AVR,ANG, ANB. 8 TP ANR,ANG, ANB The signal generator should be used via 75 ohms. (specs in desinging : 75.0 ± 0.2ohms) 0.65V ± 0.02V 3.9V ± 0.2V The first-step A = 0.50V ± 0.1V A1 A= (A1+A2)/2 A2 13 Gamma 2 verification Apply a 10-step signal to TP ANR,ANG,ANB. TP VG The input 10-step signal has no setup. If the measured value is out of specs, change the setting of SA24h D11 - 8 (γ 2 inflection point: GAMMA2 in the line adjustment 1 mode) (Register setting specs: 6 ± 1) The 10-step A = 3.00V ± 0.15V A1 A= (A1+A2)/2 A2 4.50V ± 0.20V Input waveform verification (SYNC) Apply a sync- hronizing signal to TP NVSYNC. 9 TP NVSYNC 3.3V ± 0.1V www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 180 1 2 3 4 1 2 3 4 C D F A B E No Adjustment item Input B SUB BRIGHT R SUB BRIGHT Apply a 10-step signal to TP ANR,ANG, ANB. 14 Adjust the first step levels of the G waveform and the B waveform. Adjusting point Measuring method and specs. Remarks Measuring point TP VG and VB Register setting of SA39h D11 - 8 Register setting of SA26h D7 - 1 Register setting of SA39h D15 - 12 Register setting of SA26h D15 - 9 Register setting of SA22h D15 - 8 B SUB CONTRAST R SUB CONTRAST Apply a 10-step signal to TP ANR,ANG, ANB. 15 TP VG and VB Register setting specs : 8 ± 2 (specs in designing: 8 ± 1) In the Line adjustment 2 mode, SUB BRI B can be used as the adjusting point. Register setting specs: 64 ± 3 (specs in designing: 64 ± 2) In the Line adjustment 2 mode, SUB CON B can be used as the adjusting point. Apply a 10-step signal to TP ANR,ANG, ANB. 16 17 TP VG and VR Register setting specs: 8 ± 2 (specs in designing: 8 ± 1) In the Line adjustment 2 mode, SUB BRI R can be used as the adjusting point. Register setting specs: 64 ± 3 (specs in designing: 64 ± 2) In the Line adjustment 2 mode, SUB CON R can be used as the adjusting point. Adjust the first step levels of the G wave form and the R waveform.(Measuring point is the same as that of No,14.) Adjust the 10th step levels of the G waveform and the R waveform.(Measuring point is the same as that of No,15.) Keep the unit in the operation mode for 30 minutes or longer. Adjust so that the flickers become minimum in all Apply a 10-step signal to TP ANR,ANG, ANB. TP VG and VR Register setting of SA2Ah D3 - 0 Horizon dot position 18 After being written in,the setting value of EEP-ROM is checked. 2 mode, DOT CLK can be used as the adjusting point. 6(0110) Any input signal Adjust the 10th step levels of the G waveform and the B waveform. 19 Aging Any input signal 20 Flicker Input a signal for alternate white and black lines to TP ANR, TP ANG and TP ANB. Screen Flicker adjustment has been deviated The images flicker. If it input a signal for alternate white into TP CVBS, it is possible. (However, adjustment by RGB has priority.) The luminance level of the input signal: 50%. In the flicker adjustment mode, COM DC can be used as the adjusting point. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 181 5 6 7 8 5 6 7 8 C D F A B E No 21 22 23 Adjustment item Input Measuring method and specs. Remarks Measuring point Adjusting point BACK LIGHT DRIVE FREQUENCY FREQUENCY CHANGE CHECK FREQUENCY CHANGE CHECK Apply 14.4V ± 0.2V to TP VFL TP GNDFL : GND TP INVPUL : GND TP DIMDTY : GND TP INVBST : GND Apply wave of 98.0 ± 1kHz to TP INVPUL TP : FLP2 TP : FLW2 VR 5331 48.0 ± 0.1kHz 49.0 ± 0.5kHz 52.0 ± 0.5kHz 10 ± 2% 5V 0V Apply wave of 104.0 ± 1kHz to TP INVPUL 10 ± 2% 5V 0V 100k ohms is connected between TP FLP2 and TP FLW2. It acts as the monitor of the waveform after potential. Don't acts as the monitor of the TP FLW2 directly. (there is a possibility that a measuring instrument may be destroyed, for high voltage.) Out of spec., when frequency change of following may become It checks that the waveform after potential is set to 49 kHz It checks that the waveform after potential is set to 52 kHz TP : FLP2 TP : FLW2 TP : FLP2 TP : FLW2 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 182 1 2 3 4 1 2 3 4 C D F A B E External light of dimmer adjustment(H) Back light of dimmer adjustment(H) External light of dimmer adjustment(M) Back light of dimmer adjustment(M) External light of dimmer adjustment(L) Back light of dimmer adjustment(L) Don't care -EEPROM setting mode [Operations] To enter the setting mode, while keeping the EPRTEST terminal at "Low", Flicker adjustment mode Line adjustment 1 mode Line adjustment 2 mode Dimmer parameter setting mode [ ↑ ↓ ] button: Used to select a desired adjustment item in each mode [ ←→ ] button: Used to adjust the selected item Notes: 1) The setting values are written in the EEPROM and then the read-out data is displayed on the screen. WRITE and READ operations are processed by the block data of 16 bits. The total bits for the settings depend on adjusting items. 2) For CS (Check Sum) items, when the settings are changed, the CS value is written in 8 bits by applying the exclusive OR (XOR). The CS value is first written in the EEPROM and then the read-out data is displayed. If the written data is different from the read-out data, the letter color for the read-out data is changed. Common reverse output center(Reference) Clock phase adjustment initial value Don't care Don't care Don't care - Memory items and addresses on the EEPROM(S-29221BROI-J8T1) EEPROM address Bit15 Bit14 Bit13 Bit12 Bit11 Bit10 Bit9 Bit8 Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0 00H Dimmer external light threshold (low) 01H Backlight output (upper limit) Common reverse output center (COM DC) PIP SA:22h[B15-8] γ 3 inflection point (GAMMA 3) PIP SA:24h[B15-12] Output sub contrast R (SUB CON R) PIP SA:26h[B15-9] γ 2 inflection point (GAMMA 2) PIP SA:24h[B11-8] Output clamp DC (RGB BIAS) PIP SA:23h[B13-8] Don't care Dimmer external light threshold (high) Backlight output (lower limit) 02H Common reserve output amplitude (COM AMP) PIP SA:22h[B7-2] γ 0 inflection point (GAMMA 0) PIP SA:23h[B3-0] γ 1 inflection point (GAMMA 1) PIP SA:24h[B7-3] Output sub contrast B (SUB CON B) PIP SA:26h[B7-1] 03H 04H 05H 06H 07H 08H 09H-1BH 1CH 1DH 1EH 1F-3F Don't care Clock phase adjustment (DOT CLK) PIP SA:2Ah[B3-0] Sharpness (SHARPNESS) PIP SA:05h[B2-1] Don't care Don't care Don't care Don't care Don't care Don't care Don't care Don't care Don't care Sub brightness R after γ circuit (SUB BRI R) PIP SA:39h[B15-12] Sub brightness B after g circuit (SUB BRI B) PIP SA:39h[B11-8] Check sum address (00h-1bh) 40 41 42 43-7F Don't care Don't care *) Since this product does not have OSD IC, OSD for adjustment is displayed by using GGF1416 at the time of monitor adjustment. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 183 5 6 7 8 5 6 7 8 C D F A B E Item Meaning initial value(hex) COM_DC Common reverse output center 8C COM_AMP Common reverse output amplitude 1E RGB_BIAS Out clamp DC 00 GAMMA0 γ 0 02 GAMMA3 γ 3 04 GAMMA2 γ 2 06 GAMMA1 γ 1 11 SUB_CON_R Output sub contrast R 40 SUB_CON_B Output sub contrast B 40 SUB_BRI_R Sub brightness R after γ circuit 08 SUB_BRI_B Sub brightness B after γ circuit 08 DOT_CLK Clock phase adjustment 06 SHARPNESS Sharpness 03 BL_MAX Back light output (Max.) C4 BL_MIN Back light output (Min.) 60 REF_HIGH Dimmer (H) B0 REF_LOW Dimmer (L) 50 LUM_HIGH External light (H) E2 LUM_MID External light (M) 87 LUM_LOW External light (L) 43 BL_HIGH Back light (H) C4 BL_MID Back light (M) C4 BL_LOW Back light (L) 70 EEPROM initial value initial value(DEC) 140 30 00 02 04 06 17 64 64 08 08 06 03 196 96 176 80 226 135 67 196 196 112 (1) Flicker adjustment mode [0 - 255] 255 COM DC Adjustment item Common reverse output center Adjustable name Adjustment range Settings or written data g written data g (DEC) [Displays in each mode] In the following figures, the letters and numbers surrounded by a large square are for OSD examples. On the screen, the adjustment names and the settings (or written data) are listed. The settings (or written data) will change when some adjustments are made in each mode. * The following examples show the maximum values. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 184 1 2 3 4 1 2 3 4 C D F A B E (2) Line adjustment 1 mode Adjustment item Bright (SA22: B7-2) Contrast (SA25: B7-1) Common reverse output center Common reverse output amplitude Output clamp DC γ 0 inflection point γ 3 inflection point γ 2 inflection point γ 1 inflection point Adjustable name Adjustment range Settings or written data (DEC) [0 - 63] [0 - 127] [0-255] [0-63] [0-63] [0-15] [0-15] [0-15] [0-31] 63 127 255 63 63 15 15 15 31 BRIGHT CONTRAST COM DC COM AMP RGB BIAS GAMMA0 GAMMA3 GAMMA2 GAMMA1 LINE1 FF CS Notes: 1) CONTRAST data The CONTRAST data is adjustable, and used as reference data for other adjustment items, which is not memorized in the EEPROM. 2) BRIGHT and COM AMP data The BRIGHT and COM AMP adjustments are made by using the same 2-screen IC register(SA22h B7-2: common reverse output amplitude). Therefore, adjusting one of the data will change the other one. (3) Line adjustment 2 mode [0 - 63] [0 - 127] [0 - 127] [0 - 127] [0 - 15] [0 - 15] [0 - 15] [0 - 3] Adjustment item Bright (SA22: B7-2) Contrast (SA25: B7-1) Output sub contrast R Output sub contrast B Sub brightness R after γ circuit Sub brightness B after γ circuit Clock phase adjustment Sharpness Adjustable name Adjustment range Settings or written data (DEC) Notes: 1) CONTRAST data The CONTRAST data is adjustable, and used as reference data for other adjustment items, which is not memorized in the EEPROM. 2) SUB BRI R and SUB BRI B data The displayed value or EEPROM written data is different from the setting value for the 2-screen IC register (IC4001 : TC90A64AF-P). (Before displayed on the screen, the setting value is converted via some software.) (MAX) (TIP) (MIN) Displayed value (adjusting value) (DEC) 15 14 9 8 7 1 0 15 14 9 8 7 1 0 0111 0110 0001 0000 1111 1001 1000 E2PROM written value. (DEC) 2-screen IC register setting (BIN) BRIGHT CONTRAST SUB CON R SUB CON B SUB BRI R SUB BRI B DOT CLK SHARPNESS 63 127 127 127 15 15 15 3 CS LINE2 FF www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 185 5 6 7 8 5 6 7 8 C D F A B E (4) Dimmer parameter setting mode Adjustment item Backlight output (MAX) Backlight output(MIN) Dimmer threshold (high) Dimmer threshold (low) External light point (high) External light point (middle) External light point (low) Backlight point (high) Backlight point (middle) g Backlight point (low) g p Adjustable name Adjustment range Settings or written data g written data g (DEC) [0 - 255] [0 - 255] [0 - 255] [0 - 255] [0 - 255] [0 - 255] [0 - 255] [0 - 255] [0 - 255] [0 - 255] FF FF FF FF FF FF FF FF FF FF BL MAX BL MIN REF H REF L LUM H LUM M LUM L BL H BL M BL L DIMMER FF CS Note: The dimmer point data is memorized in the EEPROM, but not treated as a CS item. It's because the settings are adjustable by the user. p g - Dot Clock Adjustment Mode [Operations] . [Dot Clock adjustment mode] starting procedure . microcomputer OFF. . . [ u i ] button : Used to select a desired adjustment item in each mode. . [ r t ] button : Used to adjust the selected item. [EEPROM : S-29221BROI-J8T1] The setting values are written in the EEPROM and then the read-out data is displayed on the screen. WRITE and READ operations are processed by the block data of 16 bits. [Display] In the following figures,a large square are for OSD examples. * CS(Check Sum)display is not performed. Dot Clock adjustment mode Adjustment item Clock phase adjustment Clock phase adjustment (initial) Common reverse output center Common reverse output center adjustment (initial) Adjustment range Settings or written data g written data g (DEC) [0 - 15] [0 - 15] [0-255] [0-255] 15 8 255 140 DOT CLK [FACTORY COM DC [FACTORY ] ] Adjustable name www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 186 1 2 3 4 1 2 3 4 C D F A B E 6.7 TEST MODE 1. How to start the test mode 1. When +Battery and ACC are ON, push RESET and EJECT buttons simultaneously. 2. Release RESET button only. 3. When “password entry screen” is displayed, release EJECT button. 4. Enter the password. 5. When the password has been entered, press [ENTER] key. 6. If the correct password has been entered, the test mode menu will be displayed. * The password entry screen, as the one used in the previous model, is no longer displayed. << Password for the service >> The password is [ (up)] [ (up)] [ (down)] [ (down)] [ENTER]. If 8 digits or more are entered and [ENTER] key is pressed, it will be treated as a password error. • Password entry screen • Password OK : After 2 seconds or so, the screen will automatically move on to the menu screen. • Password NG : Nothing will be displayed, and reboot action will be taken. Please push the [RESET] button. This is a specal service application Not for customer use. Please input the whole password,then push the [OK] button. A B C D E F G H I J K L M N O P Q R S T U V W X Y Z Password Right. Go to next page. - NAVIGATION TEST MODE www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 187 5 6 7 8 5 6 7 8 C D F A B E 1. Remocon touch panel test 3. Error log 4. Format FLASH drive 2. Version check 6. Clear backup memory 7. GPS backup data clear 8. GYRO SENSOR INFO data clear 9. Port status information ==> next page SYSTEM Ver. : [BOOT] 0.14 [OS] 0.14 TESTMODE MENU [SERVICE_MENU(THCHNICAL)] Content if inspection Calibration setting and remote controller inspection are performed. Display of various version information. (system software, GPS, system microprocessor, microprocessor for mechanism control, microprocessor for timer). The screen will return to “menu” by BACK key. History of system software errors stored in SRAM is displayed. Maximum 8 events from the error last occurred can be displayed. The screen will return to “menu” by BACK key. FLASH domain used by the system soft is initialized. When the job is done, the screen will return to “menu”. Application file inside FLASH is clear. *(Except voice data and SRAM backup variable) When the job is done, the screen will return to “menu”. SRAM domain used by the system software is initialized. When the job is done, reboot action will be taken. SRAM domain used by GPS is initialized. When the job is done, the screen will return to “menu”. Learned data inside gyro sensor is cleared. When the job is done, the screen will return to “menu”. Port status is displayed. (reverse, parking, pulse, SDRAM capacity.) No. 1 2 3 4 5 6 7 8 9 Inspection item Remocon touch panel test Version check ERROR log Format FLASH drive Erase APL-file in FLASH Clear backup memory GPS backup data clear GYRO SENSOR INFO data clear Port status information Outline of inspection Remote controller touch panel inspection Version information check Error history entry FLASH format Application file inside FLASH is clear Back up variables initialization GPS back up data clear Learned data inside gyro sensor is clear Port status display 2. Test mode menu 5. Erase APL-file in FLASH www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 188 1 2 3 4 1 2 3 4 C D F A B E 1. Change to display error [Message] 3. Program loading 4. GPS assessment 2. Start within debug shell [Disc & Card] [On] 5. File maintenance 6. Program forced write <== back page ==> next page SYSTEM Ver. : [BOOT] 0.14 [OS] 0.14 TESTMODE MENU [SERVICE_MENU(THCHNICAL)] Content if inspection Display setting for error cases. (for debugging) Message/Information (error information) selectable. Setting for debug shell start. (for debugging) Off (no initial start)/On (initial start) selectable. Recognition method for boot up program write is changed. Disc (default) Disc & Card (for debug) GPS assessment system can be used. The system will return to “menu” by BACK key. File maintenance operations are made. Formatting of SRAM drive and PC card (ATA Flash Card) are made. SRAM data is retrieved and copied to PC card. Data retrieved from SRAM is copied to SRAM from PC card. Rewriting of SYS (system), GPS (GPS) and APL (application) software are done by force. (Joystick is used) The system will return to “menu” by BACK key. No. 1 2 3 4 5 6 Inspection item Change to display error Start within debug shell Program loading GPS assessment File maintenance Program forced write Outline of inspection Switching of error information display Switching of debug shell start Switching of program loading GPS assessment system start File maintenance function Program forced write Write when the version No. in the disc is higher. Write when the version No. in the disc is higher. Write when the version No. in the disc is higher. Write when the version information is different from the one in disc. Write when the version No. in disc or card is higher. Write when the version No. in disc or card is higher. Write when the version No. in disc or card is higher. Write when the version No. in disc or card is higher. System program System data GPS program Application program System program System data GPS program Application program www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 189 5 6 7 8 5 6 7 8 C D F A B E 1. SRAM / SDRAM test 3. RGB test 2. SENSOR test 4. MS3 check <== back page ==> next page SYSTEM Ver. : [BOOT] 0.14 [OS] 0.14 TESTMODE MENU [SERVICE_MENU(THCHNICAL)] Content if inspection SRAM : Device inspection and bus inspection are performed against all SRAM domains. Data will be protected. (applicable to both 32M and 64M) SDRAM : Device inspection and bus inspection are performed against all SDRAM domains. Data will be protected for both BIOS domain and USER domain. The function for SDRAM all domain inspection will activate by the built-in instruction RAM. G sensor, gyro, power supply voltage and installation condition are displayed. The system will return to “menu” by BACK key. RGB inspection (Upper half, 8 colors. Black/blue/red/pink/green/light blue/yellow/white display. Lower half, 3 colors. Red/green/blue.) red (FULL) green (FULL) blue (FULL) Switching can be made by [ ] and [ ] keys. The system will return to “menu” by BACK key. MS3 mechanism test mode inspection. No. 1 2 3 4 Inspection item SRAM/SDRAM test SENSOR test RGB test MS3 check Outline of inspection Memory inspection Sensor inspection Image RGB inspection MS3 check [ROM] 3. How to select test mode menu Select a desired menu by [ ] and [ ] keys, and execute by pressing [ENTER] key. Pages can be changed by [ ] and [ ] keys. 4. Version information Version No. for BOOT section = X.XX System software does not exist in SDRAM. Version No. for BOOT section = X.XX Version No. for SDRAM = Y.YY www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 190 1 2 3 4 1 2 3 4 C D F A B E *) When inspecting the touch panel, use something thin with a round tip such as the touch pen. Furthermore, do not apply excessive force to the touch panel. Main Menu “*” mark shown on the left side of menu item “1” indicates that the setting has been completed. The setting items where “*” is actually indicated will be “1. Setup ~” and “2. Setup ~” only. [CR] Enter [UP/DOWN] Selection of the inspection item [BACK] Return (to the test mode menu) 1. Setup touch-panel effective range Explanation of the displays min_x(A,B) : X coordinate of the touch panel • minimum value received max_x(A,B) : X coordinate of the touch panel • maximum value received min_y(A,B) : Y coordinate of the touch panel • minimum value received max_y(A,B) : Y coordinate of the touch panel • maximum value received ### Remocon / Touch-panel Test ### 1. Setup touch-panel effective range 2. Setup calibration 5. Check Touch-panel compensation 6. Check Touch-panel graphics 7. Check Touch-panel navi coordinate [JS UP / DOWN] [BACK] [CR] Cursor movement Back to menu Menu selection ### Setup touch-panel effective range ### The present of the touch-panel effect range (before. after) Please trace a white line. Please move to calibration setup after this setup. max Y : (210, 211) min Y : ( 36, 36) min X : ( 37, 36) max X : (230, 232) - Remocon touch panel test 1) Trace the edge of the screen along the monitor resin frame with a round-headed thing to obtain the coordinates. 2) Press the [BACK] key. Adjustment steps 3. Test Touch-panel 4. Check now calibration condition • How to operate the touch panel test mode is described below. • First, “1. Setup touch-panel effective range“ in the touch panel test menu is made. • Next, “3. Test Touch-panel“, and if the result is OK, then EXIT the screen. • If the result is NG, conduct “2. Setup calibration“, and conduct “3. Test Touch-panel“ once again. If the result is OK, then EXIT the screen. • Furthermore, details of the misalignment can be verified by the “5. Check Touch-panel compensation“. * www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 191 5 6 7 8 5 6 7 8 C D F A B E 2. Setup calibration Explanation • A [+] cursor is displayed at 16 locations on the screen for calibration. Finally, verification of a single point is made. The cursor is always displayed at one location only, and moves on to the next location as the current one is correctly pressed. • When pressing on the [+] cursor, make sure to press at the center of “+”. • The result of calibration will be recorded in the SRAM. • If effective operation is not made for 30 seconds, the system will recognize as “erroneous end” and stops the calibration. A = A coordinate which is already stored in the SRAM (If there is no previous data in the SRAM, “min=90, max=180” will be displayed). B = An updated coordinate which is planned to be set in the SRAM this time (If there is no previous data in the SRAM, “min=90, max=180” will be displayed). [BACK] : The preset effective range is registered, and the screen will return to the remote controller inspection menu. The data of the effective range will be recorded in the SRAM. In case the compensation value is not preset in the SRAM, the following initial (default) value will be entered automatically at the time of navigation system boot up. min_x = 42 (right edge limit value) max_x = 246 (left edge limit value) min_y = 49 (bottom edge limit value) max_y = 238 (top edge limit value) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 192 1 2 3 4 1 2 3 4 C D F A B E 3. Test Touch-panel Explanation on touch panel misalignment verification test. 1) The test is intended to verify if the touched point on the touch panel is correctly recognized or not. [+] cursor will be displayed at 16 locations on the screen. The cursor will be displayed in “white color“ only one at a time. Each time the cursor is touched correctly, the next point will be displayed. On the other hand, if it is recognized that the point touched was ±4 dots vertically and ±5 dots horizontally away from the center of the displayed [+] cursor, the erroneously recognized coordinate [+] will be drawn in “red color“. 2) When touching the [+] cursor, touch the center of the + mark correctly. 3) If [BACK] is touched, the test will be finished, and the screen will return to the menu screen of the touch panel test mode. If this test turns out to be NG, it will be necessary to redo “1. Setup touch-panel effective range“ and “2. Setup calibration“. Repeat the above steps once again. 4. Check now calibration codition Explanation on the setting status of the calibration compensation value. The current calibration compensation status is displayed. The following data will be displayed. “With no calibration value” (in white characters) In case the compensation value does not exist in the SRAM. “The effective range value is stored” In case the compensation value for the upper limit and the lower limit are preset in the SRAM. “The calibration compensation value is stored” In case the calibration compensation values for the 16 points are preset in the SRAM. “The effective range & calibration value is stored.” In case the upper limit and the lower limit values and the 16 points calibration values are preset in the SRAM. “The initial value is substituted.” In case the value stored as the initial (default) value is preset in the SRAM. “Error Condition” In case the SRAM value is demolished or some unexpected situation is happening. ### Test Touch-panel ### [BACK] Return ### The current calibration state ### [BACK] Return menu The initial value is substituted. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 193 5 6 7 8 5 6 7 8 C D F A B E 5. Check Touch-panel compensation [BACK] : The system will return to the remote controller inspection menu. Explanation of the inspection details • Regarding this inspection, the title only will be displayed at the initialized stage. • As shown by the arrow, press any desired location on the monitor. • A coordinate after the calibration correction will be displayed by the [+] mark against the coordinate recognized as pressed. 6. Check Touch-panel graphics [NAVI] + pressing the touch panel : The coordinate of the touch panel at that time will be displayed. [ ] : Horizontal line will move upward. [ ] : Horizontal line will move downward. [ ] : Vertical line will move to the left. [ ] : Vertical line will move to the right. [BACK] : The system will return to the remote controller inspection menu. Explanation of the displayed coordinate (from top to bottom) (79, 80) : Coordinate of the crossing point by the vertical and the horizontal lines (X direction, Y direction). [(0~500, 0~240)] (0, 0) : AD data value (X direction, Y direction) representing the coordinate of the pressed location received from the system control microprocessor. (0, 0) : Coordinate (X direction, Y direction) obtained by normalizing the AD data value of the pressed location within the effective range. (0, 0) : Coordinate (X direction, Y direction) obtained by adding the correction based on calibration to the normalized coordinate. ### Compensation check test ### [BACK] Back to menu ### Touch-panel coordinates test ### [POSITION + ] Display of the cood nates pushed [BACK] Return menu After calibration Coversion effective Cross drawing dot From system CPU : : : : ( 0, 0) ( 0, 0) ( 79, 80) ( 0, 0) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 194 1 2 3 4 1 2 3 4 C D F A B E 7. Check Touch-panel navi coordinate [BACK] + pressing the touch panel will make the system return to the remote controller inspection menu. Explanation of the displayed content. panel x_before : X coordinate normalized (expanded) within the effective range. panel y_before : Y coordinate normalized (expanded) within the effective range. panel x_after : X coordinate obtained by adding the correction based on calibration. panel y_after : Y coordinate obtained by adding the correction based on calibration. ### Remocon test ### return to amenu by [DEST] and [TOUCH-PANEL] panel y_after = 53 panel x_after = 28 panel x_before = 35 panel y_before = 55 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 195 5 6 7 8 5 6 7 8 C D F A B E - Version check VERSION INFORMATION 2. System OS version 3. GPS program version 4. Application version 6. Syscom version 7. Syscom romc version 8. Drive atapi version 9. Monitor ucom version 10. Monitor ucom romc version 1. System boot version [ 0.10 ] [ 0.10 ] [ 0.010000 ] [ 0.010000 ] [ 0.10 ] [ ------ ] [ ver 4042 ] [ 1.00 ] [ ------ ] [ 0.10 ] Return = [BACK] File name UC050BOT.USA UC050SYS.USA UC050GPS.PRG EU050APL.PRG UC050DAT.USA UC050SYS.USA UC050DAT.USA 1 2 3 4 5 6 7 8 9 10 11 12 Item System boot version System OS version GPS program version Application version Language data version Syscom version Syscom romc version Drive atapi version Monitor ucom version Monitor ucom romc version System language Application language Content Version information of the system software BOOT section (FLASH) is displayed. Version information of the system software OS section (FLASH) is displayed. Version information of the GPS program (DRAGON) is displayed. Version information of the application program (SDRAM) is displayed. Version information of the language data (FLASH) is displayed. Version information of the system microprocessor is displayed. Version information of the system microprocessor ROM collection is displayed. Version information of the microprocessor of MS3 is displayed. Version information of the microprocessor of monitor is displayed. Version information of the monitor microprocessor ROM collection is displayed. Language of the system program (FLASH) is displayed. Language data file is displayed. Information display [**.**] Version information of the system software BOOT section. [**.**] Version information of the system software OS section. [NG] System program does not exist. [**.**] Version information of the GPS program. [NG] GPS program does not exist. [**.**] Version information of the application program. [NG] Application program does not exist. [**.**] Version information of the language data. [NG] language data does not exist. [**.**] Version information of the system microprocessor. [NG] Communication with the system microprocessor has not been established. [**.**] Version information of the system microprocessor ROM collection. [------] No connection of ROM collection. [**.**] Version information of the microprocessor of MS3. [NG] Communication with the microprocessor of MS3 has not been established. [**.**] Version information of the microprocessor of monitor. [NG] Communication with the microprocessor of monitor has not been established. [**.**] Version information of the monitor microprocessor ROM collection. [------] No connection of ROM collection. [**.**] System program file. [NG] System program does not exist. [**.**] Language data file. [NG] Language data does not exist. 5. Language data version + www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 196 1 2 3 4 1 2 3 4 C D F A B E 1. Error Information Descriptions of error information, for errors arising from system software problems, will be provided in this section. Up to eight sets of information, related to the system software’s errors, will be stored in the SRAM. By executing hi_sysdwn( ) the line number (on which the error occurred), the error code and detailed information of the error, will be stored in the error log. r Hi_sysdwn( ) will be executed in the following two circumstances: 1. hi_sysdwn( ) will be intentionally stored if fatal errors occur with each BIOS. 2. If multiple exceptions, fatal exceptions, illegal command codes and trap command errors occur. 2. Error Log's Entry Function Up to twenty-four sets of information, related to errors starting with the latest error, will be displayed by the error log entry function. There are two types of error log displays. The display will vary when the argument provided to hi_sysdwn( ), depending on whether detailed information (such as program name, version number, creation date, creation time and creator name) exists or not r, creation date, creation time and creator name) exists or not. 1. When detailed information exists: ERCD Error code. FILE Error occurring program name. g g LINE Error occurring program line number g g . VERS Error occurring program version number g g . DATE ATE A Error occurring program creation date. g g TIME Error occurring program creation time. g g AUTH Error occurring program creator name. g g ERROR-TIME Error occurrence date and time. - Error Information ERROR INFORMATION ATION A ** ** ERROR INFORMATION A ERCD DA AUTH ERROR-TIME ffff-ff-ff ff:ff:ff No.4 ERROR No.3 No.2 Stop when push [BACK] button. 00000028(40) 06:07:26 daisuke = = = = = = = www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 197 5 6 7 8 5 6 7 8 C D F A B E 2. When detailed information does not exist: type Error occurring program line number. ercd Error code. inf System down information. ERROR-TIME Error occurrence date and time. If an error occurs due to a multiple exception, the definitions will change to the following: type Execution address at the time of error occurrence. ercd Contributing factor for the exceptions. inf Program status word at the time of error occurrence. ERROR-TIME Error occurrence date and time. 3. Error Information Switch The product (with default settings) will display error messages to the user if an error occurs. Error information can be displayed if an error occurs by switching the error information in the test mode. In either case, the error log entry display will be the same. 1) Error message display (default settings): • Setting in the test mode: ERROR INFORMATION ** ** type = 000000b7(183) ercd = ffffc002(-16382) inf = ffb7ac18(-4740072) ERROR-TIME ffff-ff-ff ff:ff:ff No.2 ERROR No.1 No.24 Stop when push [BACK] button. TESTMODE MENU [SERVICE_MENU(TECHNICAL)] 1. Change to display error [Message] 2. Start within debug shell [On] 3. Program loading [Disc version] 4. GPS assessment 5. File maintenance 6. Program forced write <== back page ==> next page SYSTEM Ver. : [BOOT]0.65 [OS]0.65 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 198 1 2 3 4 1 2 3 4 C D F A B E • Display when an error occurs: 2) Error information display • Settings in the test mode: Display when an error occurs: • If error information exists: An error has occured. Please turn power off and on again. TESTMODE MENU [SERVICE_MENU(TECHNICAL)] 1. Change to display error [Information] 2. Start within debug shell [Off] 3. Program loading [Version up] 4. GPS assessment 5. File maintenance 6. Program forced write <== back page ==> next page SYSTEM Ver. : [BOOT]0.65 [OS]0.65 ERROR INFORMATION ** ** ERCD FILE LINE VERS DATE TIME AUTH ERROR-TIME ffff-ff-ff ff:ff:ff f f f f f f f f(-1) tsk_ini.c 152(00000098) 1.11 2003/04/03 04:59:10 jin = = = = = = = Une erreur a ete decelee. Veuillez eteindre puis rallumer le systeme. Fehler. Bitte System aus- und wieder einschalten. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 199 5 6 7 8 5 6 7 8 C D F A B E • If error information does not exist: ERROR INFORMATION ** ** type = 00000109(265) ercd = 00000001(1) inf = ffe83230(-1560016) ERROR-TIME ffff-ff-ff ff:ff:ff 4. Watch dog timer This product has a built-in mechanism to monitor at a certain interval whether the software is correctly operating or not. Once this mechanism becomes inoperable, “reset request” will be sent to the power supply microprocessor when a preset time (approximately 4 seconds) has elapsed. In order to record operational situation of such an occasion, a special code which is not an error code is recorded in the ERCD. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 200 1 2 3 4 1 2 3 4 C D F A B E - Port status information Port status information Parking Pulse Reverse Low 0 Low [NAVI] information renewal. [BACK] go to testmode menu. How to operate. [BACK] : Return to the test mode menu. [NAVI] : Update of the port status. Display Reverse Parking Pulse Content of inspection Reverse port status Parking port status Pulse status - GPS assessment GPS TEST GPS SENSOR FLASH :Ver. 3. 09 :Ver. 5. 56 :Ver. 0. 10 02 / 03 / 12 02 / 05 / 10 Press [BACK] to return Display of DRAGON FLASH ROM version information. Display of GPS version information. Display of sensor version information. FLASH GPS SENSOR The pulse number of vehicle speed is indicated at 1/5 value of input frequency for vehicle speed signal. For example, when vehicle speed signal is 100Hz, the value becomes 20. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 201 5 6 7 8 5 6 7 8 C D F A B E SENSOR TEST GYRO POWER G-SENSOR : : : 2.4804 [V] 1.9875 [V] FIT UP DISTANCE : : OK(Best) 14.9453 [V] LOW SPEED : OK SPEED PULSE Press [BACK] to return - SENSOR test Display of G sensor voltage Display of gyro voltage Display of power supply voltage Display of installation status Display • NG • OK • OK (Better) • OK (Best) Display of distance calculation status. Display • INITIALIZE • GPS • G-SENSOR • ND-PG1 • SPEED PULSE Display of minimum output speed of a low speed NG vehicle. (Depends on DISTANCE status.) DISTANCE status SPEED PULSE Others G-SENSOR GYRO POWER FIT UP DISTANCE LOW SPEED Status Installation position is NG. Installation position is OK. (3rd best) Installation position is OK. (2nd best) Installation position is OK. (Best) Status Sensor initial learning is under way. GPS distance. (Model without G sensor. No pulse connection.) G sensor distance. (simple hybrid.) ND-PG1 distance. Vehicle speed pulse distance. SPEED PULSE status Low vehicle speed pulse learning is under way. Low vehicle speed pulse is OK. Low vehicle speed is NG. Display CHECK OK NG xx[km/h] - - - - - www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 202 1 2 3 4 1 2 3 4 C D F A B E 1. Test mode starting procedure Please select "MS3 check" to start test mode. 2. Keys used for the DVD test mode 3. Test mode flow chart MS3 check Start DVD/CD test (Set source to DVD) EDC-1 mode test EDC-2 mode test FE test Power Off Focus close Focus search CRG +/- LD ON/OFF CRG home Focus search STOP Power Off Tracking balance CRG +/- Power Off Tracking close CRG +/- Power Off Error rate measurement Reproduction speed switching Focus jump Tracking jump / ID search Tracking open ID specification Jump start / ID search start Track number specification Tracking Close condition Focus Close condition 2 Focus Close condition 1 Power ON condition Power OFF condition [ Display data of adjustment value ] FEOFS : FE offset coefficient TEOFS : TE offset coefficient ASOFS : AS offset coefficient ENOFS : ENV offset coefficient DBAL : DBAL coefficient [ Display data of adjustment value ] FEMAX : FE MAX level FEMIN : FE MIN leve ASMAX : AS MAX leve ENMAX : ENV MAX leve FEORG : FE normalize coefficient MGA : Spindle gain coefficient [ Display data of adjustment value ] TBAL0 : TBAL coefficient (layer-0) TBAL1 : TBAL coefficient (layer-1) TEOR0 : TE normalize coefficient (layer-0) TEOR1 : TE normalize coefficient (layer-1) FBAL0 : FBAL coefficient (layer-0) FBAL1 : FBAL coefficient (layer-1) [ Display data of adjustment value ] FBAL0 : FBAL coefficient (layer-0) FBAL1 : FBAL coefficient (layer-1) FGA0 : Focus gain coefficient (layer-0) FGA1 : Focus gain coefficient (layer-1) TGA0 : Tracking gain coefficient (layer-0) TGA1 : Tracking gain coefficient (layer-1) ASAT0 : AS normalize adjustment value (layer-0) ASAT1 : AS normalize adjustment value (layer-1) [OK] : Selection decided. [BACK] : Go back. Directional keys : [ ] keys [Display data of adjustment value] BLANK - DVD Test Modes www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 203 5 6 7 8 5 6 7 8 C D F A B E 4. Description of test mode • [X-3055 Test Mode] : Initial screen MS3 check [OK] Make a selection [BACK] Return Please select a disc type. 1. DVD ( Single layer ) 2. DVD ( Dual layer ) 3. CD-ROM • [X-3055 Test menu] : Main menu screen [Direction + Enter] [1] Starts FE test mode. [2] Starts EDC-1 mode test. [3] Starts EDC-2 mode test. [Return] Returns to the test mode menu. MS3 check - DVD ( Dual layer ) [OK] Make a selection [BACK] Return Status : Power off Display data : 1. FE test 2. EDC-1 mode test 3. EDC-2 mode test Model : DVD-ROM ATAPI Model X-3055 Firm : ver 8.01 Status Model Firm : "Power off" under normal condition. : Model name of the drive being used. : Version number of the drive being used. [Direction + Enter] [1] Starts DVD (single layer) test. (Use a single layer DVD disc.) [2] Starts DVD (dual layer) test. (Use a dual layer DVD disc.) [3] Starts CD test. (Use a CD disc.) [Return] Returns to the test mode menu www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 204 1 2 3 4 1 2 3 4 C D F A B E • [FE Test menu] : FE test mode menu screen [Direction + Enter] [1] Focus close (Turn the LD on before execution.) [2] Focus search (Turn the LD on before execution.) Toggle ON/OFF with [Enter] key. [3] Carriage adjustment The carriage moves outward with [→] key and moves inward with [←] key. [4] LD switching Toggle ON/OFF with [Enter] key. [5] Moves the carriage to the home position. [Return] Returns to the main menu. • [FE Test 2] : FE test mode screen (focus close) [Direction + Enter] [1] Tracking balance [2] Carriage adjustment The carriage moves outward with [→] key and moves inward with [←] key. [Return] Returns to the main menu. FE test - DVD ( Dual layer ) [OK] Make a selection [BACK] Return Status : Power on Display data : 00000001 FEOFS TEOFS ASOFS ENOFS DBAL FFBE 0100 FD82 FF80 00A5 1. Focus close 2. Focus search [ Off ] 3. CRG +/- ( Right(+) / Left(-) ) 4. LD [ On ] 5. CRG home Status Display data Adjusted value : "Power on" under normal condition. : Displays an error code in case of an error. : See the Test Mode Flow Chart for the contents of adjusted values. FE test - DVD ( Dual layer ) [OK] Make a selection [BACK] Return Status : Focus close Display data : 00000000 FEMAX FEMIN ASMAX ENMAX FEORG MGA 1CBE DD3E 1942 3900 02FD 02F9 1. Tracking balance 2. CRG +/- ( Right(+) / Left(-) ) Status Display data Adjusted value : "Focus close" under normal condition. : Displays an error code in case of an error. : See the Test Mode Flow Chart for the contents of adjusted values. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 205 5 6 7 8 5 6 7 8 C D F A B E • [FE Test 3] : FE test mode screen (tracking balance) FE test - DVD ( Dual layer ) [OK] Make a selection Status : Focus close Display data : 00000000 TBAL0 TBAL1 TEOR0 TEOR1 FBAL0 FBAL1 0000 0000 01B8 01B9 0000 0000 1. Tracking close 2. CRG +/- ( Right(+) / Left(-) ) [Direction + Enter] [1] Tracking close [2] Carriage adjustment The carriage moves outward with [→] key and moves inward with [←] key. [Return] Returns to the main menu. Status Display data Adjusted value : "Focus close" under normal condition. : Displays an error code in case of an error. : See the Test Mode Flow Chart for the contents of adjusted values. • [FE Test 4] : FE test mode screen (tracking close) FE test - DVD ( Dual layer ) [OK] Make a selection [BACK] Return Status : Tracking close Display data : 00000000 FBAL0 FBAL1 FGA0 FGA1 TGA0 TGA1 ASAT0 ASAT1 0000 E200 0200 01F2 0200 0233 031C 0333 1. Error rate [ - - - - - - - - ] 2. Read speed [ - - - - - - ] 3. Focus jump [ Layer - ] 4. Track jump / ID search 5. Tracking open ( Focus close status ) [Direction + Enter] [1] Error rate measurement Displays the error rate by index (X.XXXE-X). (Other operations cannot be executed during error rate measurement.) [2] Playback-speed switching Toggle (DVD x2.5CAV/ x1CLV, CD x10CAV/ x2CLV) with [Enter] key. Display data : 00000000 = CAVx1 00000001 = CLVx1 00000002 = CAVx10 00000003 = CLVx2 [3] Focus jump Toggle (Layer 0/1) with [Enter] key. Display data : 00000000 = Layer 0 00000001 = Layer 1 [4] Track jump/ID search Toggle ON/OFF with [Enter] key. [5] Track opening Clears the adjusted value display and moves to the focus close status. [Return] Returns to the main menu. Status Display data Adjusted value : "Tracking close" under normal condition. : Displays an error code in case of an error. : See the Test Mode Flow Chart for the contents of adjusted values. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 206 1 2 3 4 1 2 3 4 C D F A B E • [FE Test 5] : FE test mode screen (track jump/ID search) • [EDC-1/EDC-2 test menu] : EDC-1/EDC-2 Test Menu screen EDC-1 EDC-2 : Executes EDC test continuously. : Executes EDC test by block unit. [Direction + Enter] [1] Backward track jump [2] Forward track jump Select the number of tracks to be jumped with [Direction] key. Press [Enter] key to execute the jump. [3] Searching the specified layer and ID Select the layer and ID (address) to be searched with [Direction] key. Press [Enter] key to execute the search. Specify the address in "mmssff (minute: second: frame)" for CD-ROM. [Return] Returns to the tracking close status. [Return] Returns to the main menu. FE test - DVD ( Dual layer ) [OK] Make a selection [BACK] Return Status : Tracking close Display data : 00000001 FBAL0 FBAL1 FGA0 FGA1 TGA0 TGA1 ASAT0 ASAT1 0000 E200 0200 01F2 0200 0233 031C 0333 1. Track jump + 2. Track jump - 3. ID search Layer : 0 ID : 030000 EDC-1 mode test - DVD ( Dual layer ) [OK] Change ID [BACK] Return Status : Normal mode Display data : 200301C0 Please input start ID & layer. Layer : 0 ID : 030000 Status Adjusted value : "Normal mode" under normal condition. : See the Test Mode Flow Chart for the contents of adjusted values. Layer ID : Layer being tested : ID being tested [Direction + Enter] Select the layer and ID (address) of the jump destination with [Direction] key. Press [Enter] to execute the jump. Specify the address in "mmssff (minute: second: frame)" for CD-ROM. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 207 5 6 7 8 5 6 7 8 C D F A B E • Display data (Error code) : Overrun error (Communication error) : Framing error (Communication error) : Writing, setting error (An error has occurred at the time of setting M62 CRAM, a command, etc.) : Parameter error (Set parameter is invalid.) : Command error (Set command is invalid.) : Command uncompleted : Decode normally completed (Decode has been normally completed from the specified ID to the final target ID in EDC mode.) : Hard reset or soft reset The followings are valid only during error rate measurement or in EDC mode : Media Load or Eject Failed (Mechanical error) : High Temperature (High temperature sense) : Voltage Out of Range (VD power supply failure) : Medium Not Present (No disc) : No Seek Complete (Seek failure) : Unrecovered Read Error (Formatter Error, CRC (EDC) Error, Uncorrectable Error, etc.) : Track Following Error (Servo failure) In case that the above error codes cannot be obtained, ATAPI BIOS error code will be displayed. E0000000 E0010000 E0020000 E0030000 E0040000 E0060000 E0100000 E0FFFF00 E0015300 E0018000 E0018100 E0023A00 E0030200 E0031100 E0030900 Error code name NO_ERROR ERR_ATAPI_RSV ERR_ATAPI_DNR ERR_ATAPI_ANF ERR_ATAPI_HEAT ERR_ATAPI_MECHA ERR_ATAPI_NODISC ERR_ATAPI_PARAM ERR_ATAPI_REENT ERR_ATAPI_DISC ERR_ATAPI_TMOUT ERR_ATAPI_DATA ERR_ATAPI_EJECT ERR_ATAPI_DCHG ERR_ATAPI_MODE ERR_ATAPI_OFF ERR_ATAPI _TEST Return value 00000000H ffff1000H ffff1001H ffff1002H ffff1003H ffff1004H ffff1005H ffff1006H ffff1007H ffff1008H ffff1009H ffff100aH ffff100bH ffff100cH ffff100dH ffff100eH ffff100fH Description Completed Reserved Device has not been prepared. Device has not completed TOC search, etc. The target address has not been found. The device temperature is out of operational range. Device cannot be operated because of any mechanical reason. Device has not been found on ATAPI bus. Disc has not been found. An error has been found in parameter or command. A reentrant prohibition violation has occurred. Disc error A command for data has been issued to an audio track. Access to an unreadable disc such as reversely inserted disc. Time out No response from device for a certain period of time. Error cannot have been corrected. Disc has been ejected. Disc change history exists. Disc change has been executed since the last command. X-3055 mode error A command for test mode has been issued in Normal mode, or other way round. ATAPI BIOS is OFF. An error has occurred with ATAPI_TEST command. [ATAPI BIOS error code] www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 208 1 2 3 4 1 2 3 4 C D F A B E ATAPI BIOS ERROR CODE ERR_ATAPI_PARAM ERR_ATAPI_ANF ERR_ATAPI_MECHA ERR_ATAPI_HEAT ERR_ATAPI_NODISC ERR_ATAPI_DNR ERR_ATAPI_DISC ERR_ATAPI_DATA ERR_ATAPI_DCHG Sense Key 0X05 Illegal Request 0X0B Aborted Command 0X05 Illegal Request 0X01 Recovered Error 0X04 Hardware Error 0X01 Recovered Error 0X02 Not Ready 0X02 Not Ready 0X06 Unit attention 0X02 Not Ready 0X03 Medium Error 0X05 Illegal Request 0X03 Medium Error 0X06 Unit attention ASC 0X24 0X1A 0X26 0X39 0X20 0X4E 0X21 0X53 0X85 0X80 0X3A 0X04 0X29 0X30 0X02 0X09 0X30 0X64 0X11 0X28 Comment Inquiry, Mode Sense, Mode Select, Read DVD Structure Mode Select Mode Select Mode Sense Seek, Read(12) [ATAPIBIOS <-> MS3 error code association table] www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 209 5 6 7 8 5 6 7 8 C D F A B E 6.8 USING THE TEST DISC 1. Start/End 1-1. Start When the test disc is inserted, the title “NN642 TEST DISC” will be displayed. If [RETURN] key is pressed while the title is being displayed, the menu screen will be displayed. If no key is pressed, the first screen of the inspection screen for line will be displayed. Title screen 1-2. End No action is taken. 2. Key operation • In the case of inspection screen for line 1. The inspection screen and the menu screen can be switched alternately using the [CR] key on the remote controller. 2. The screen will go back to the previous screen by the [ ] key on the remote controller. 3. The screen will move forward to the next screen by the [ ] key on the remote controller. (Unless the inspection is finished, the screen will not move forward. The screen will not move forward, too, if there is an NG item.) * Refer to the explanation of each screen for the details. • In the case of service menu screen 1. Select an inspection item by the [ ] and [ ] keys on the remote controller, and inspection screen will appear when the [CR] key is pressed. 2. When the [RETURN] key on the remote controller is pressed, the screen will go back to the menu screen. * Refer to the explanation of each screen for the details. NN642 TEST DISC TEST DISC Part No. : GGV1237 Part No. CXB7427 CXB7426 CXB9118 CD-R11 Description Co-packed remote controller with AVIC-8DVD/EW Co-packed remote controller with AVIC-9DVD/EW, UC Co-packed remote controller with AVIC-8DVD-2/EW, -9DVD-2/EW, -90DVD/UC Optional remote controller REMOTE CONTROLLER Part No. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 210 1 2 3 4 1 2 3 4 C D F A B E Menu screens Self Test Menu 1. External Connection 2. Data Communication (Short) 3. Data Communication (Open) 4. Natural Drawing & Rear View 5. VTR In check [CR KEY] The selected menu is started. Self Test Menu 6. GPS Self check 7. Software version display 8. Language Flag setup mode 9. Memory all cleay 10. GPS sensitivity measurement 11. Picture RGB check 12. GPS information [CR KEY] The selected menu is started. Self Test Menu 13. Sound play 14. File Maintenance mode 15. Picture check 16. Device check(Design engineer only) 17. Memory all clear (for Service) 18. BackUp Memory clear [CR KEY] The selected menu is started. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 211 5 6 7 8 5 6 7 8 C D F A B E 1. Connection check • The status of the item indicated in the above figure will be updated every second. • When the gyro is in operation, a BEEP sound will be made when the G sensor is activated. Right: 500Hz, Left: 700Hz. Up: 800Hz, Down: 600Hz • Conditions for moving on to the next inspection Illumination status is changing between ON and OFF. Parking brake status is changing between ON and OFF. Reverse status is changing between NOR and REV. Pulse is changing to a value other than 0/0. All keys on the main body as listed below have been pressed at least once. "DEST", "INFO", "MEMO", "TRAFFIC" The value of the gyro changes to right and left at least once for each. * Until it changes at least once for each, “--” is displayed even when it is OK. (ex.) When the orientation status is left rotation level 1, it is displayed as below. Heading Left 1. Connection check Illumination signal Parking brake signal Car speed signal Reverse gear signal Gyro voltage / sigma Battery voltage GSENS voltage / sigma Heading Remote controller OFF ON NOR 0 12.3V 2.450V OK / 1.1 OK 2.050V OK / 1.1 OK CONST CONST -- MENU [joy stick down] It progresses to the next inspection. Details of the error An error when communication with DRAGON cannot be established. Communication error due to a hardware problem could be the cause. It is highly possible that the hardware on the DRAGON side is defective. Time out error for response to BIOS call. Communication error due to a hardware problem could be the cause. It is highly possible that the hardware on the DRAGON side is defective. Error due to unknown reason. Displayed message No connection to DRAGON Command error Unknown error Body key Pitch 3. Inspection screen K mode OFF www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 212 1 2 3 4 1 2 3 4 C D F A B E 2. Data Communication (Short Circuit) check (Not for service) • SIO connection short is checked. • Loop back check is performed on 5CH and 7CH. • Wait screen is displayed until the checking is completed. • When [RETURN] key on the remote controller is pressed while the inspection result is being displayed on the screen, inspection will be performed once again. • Only in the case of OK, you can move on to the next inspection by the [ ] key on the remote controller. 3. Data Communication (Open Circuit) check (Not for service) • SIO connection open is checked. • Check is performed on 5CH and 7CH. • Do not connect anything to the terminal. OK will be indicated under “open” condition. • Wait screen is displayed until the checking is completed. • When [RETURN] key on the remote controller is pressed while the inspection result is being displayed on the screen, inspection will be performed once again. • Only in the case of OK, you can move on to the next inspection by the [ ] key on the remote controller. 2. Data Communication (Short Circuit) check Serial I/O #5(for Extension) Serial I/O #7(for Debug) OK OK [joy stick down] It progresses to the next inspection. 3. Data Communication (Open Circuit) check Serial I/O #5(for Extension) Serial I/O #7(for Debug) OK OK [joy stick down] It progresses to the next inspection. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 213 5 6 7 8 5 6 7 8 C D F A B E 4. Natural Drawing & Rear View • Natural image consisting of 256 colors will be drawn on the BG screen. • ADPCM 1kHz sine wave at the sampling rate of 19kHz will be output for 30 seconds. • Rear view image will be displayed on the right hand side of the screen. • Volume level can be changed by the [ ] and [ ] keys on the remote controller. (0 to 9) [JPEG file name: ZHITO1.JPEG] [Voice file name: A19K01KS.WAV] • You can move on to the next inspection by the [ ] key on the remote controller. 5. VTR check • External input image (VTR input image) is displayed and voice is outputted. • You can move on to the next inspection by the [ ] key on the remote controller. 5. VTR check [joy stick down] It progresses to the next inspection. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 214 1 2 3 4 1 2 3 4 C D F A B E 6. GPS Self check • GPS receiving status will be displayed. • Conditions to move on to the next inspection. Antenna connection is OK. Data is received from one or more satellite. Time is being displayed. • When all the conditions are met, the background color will change to blue. • Only when all the conditions are met, you can move on to the next inspection by the [ ] key on the remote controller. It should be noted, however, that you will not be able to move on to the next inspection if there is an error (background color is red) even if the conditions are met. 7. Software version • It indicates the version information of the software. • Conditions to more on to the next inspection. “GPS model” is “05UC DVD”. “Calibration check” is ”OK”. OK : ”Setup touch panel effective range” in Testmode is done. • Only when all the conditions are met, you can move on to the next inspection by the [ ] key on the remote controller. It should be noted, however, that you will not be able to move on to the next inspection if there is an error (background color is red) even if the conditions are met. 6. GPS Self check Using satellites NO. 01 02 03 04 05 06 07 08 Antenna connection Receiving signal level Latitude Longitude 2004/11/24 15:00:00 OK 13.5 3D 35 55 47.1 139 28 30.0 [joy stick down] It progresses to the next inspection. Details of the error This is an error when communication with DRAGON is not established. Communication error due to a hardware problem could be the cause. It is highly possible that the hardware on the DRAGON side is defective. Time out error for response to BIOS call. Communication error due to a hardware problem could be the cause. It is highly possible that the hardware on the DRAGON side is defective. This is an error when request is made while the data for response is not prepared (not obtained from DRAGON). Communication error due to a hardware problem could be the cause. It is highly possible that the hardware on the DRAGON side is defective. Displayed message No connection to DRAGON Command error Invalid data 7. Software version System boot / OS version Syscom version Drive apl version GPS program version GPS model 0.17 / 0.17 6.10 6.01 4032 5.08 04/04/01 4.10 DVD (0x29) [joy stick down] It progresses to the next inspection. Monitor ucom version ver 05UC Calibration check OK www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 215 5 6 7 8 5 6 7 8 C D F A B E 8. Language selection flag initialize • When the system enters into this inspection, language selection will be set to the original setting made at the time of shipment (i.e. no setting). * The setting is made to display the screen for selecting the language to be used at the initial boot up after the shipment out of the factory. • The setting is made when the system enters into this inspection. • You can move on to the next inspection by the [ ] key on the remote controller. 9. All memory clear (Not for service) • SRAM (application domain) is cleared. • FLASH (application domain) is cleared. • Sensor learning level is cleared. • If SRAM clear is not successful, FLASH will not be cleared. • After the inspection screen is displayed, the above process is executed by the [NAVI] key on the remote controller. • The result of the process is displayed. • Only when everything is OK, you can move on to the next inspection by the [ ] key on the remote controller. 8. Language selection flag initialize Language selection flag is initialize. [joy stick down] It progresses to the next inspection. 9. All memory clear The clearance of SRAM (application domain) The clearance of FLASH (application domain) Elimination of a sensor study value [NAVI] Inspection is performed. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 216 1 2 3 4 1 2 3 4 C D F A B E 10. GPS sensitivity measurement • GPS can be changed by the [ ] and [ ] keys on the remote controller. • Sensitivity of the selected GPS is displayed by the [RETURN] key on the remote controller. • Production engineering inspection is ended and service menu is displayed by the [ ] key on the remote controller. 11. Picture RGB check • RGB bridge is inspected. • The screen can be switched by the [ ] and [ ] keys on the remote controller. • RGB is drawn in the pattern of R 100% R 50% G 100% G 50% B 100% B 50%. • Total of 6 screens will be displayed. 10. GPS sensitivity measurement Satellite NO. 3 [<- -> to select satellite] [joy stick down] Raw work inspection is ended. CH. Look SNR(AMU) SNR(dB) 1 OK 12.3 23.4 2 OK 12.3 23.4 3 OK 12.3 23.4 4 OK 12.3 23.4 5 OK 12.3 23.4 6 OK 12.3 23.4 7 OK 12.3 23.4 8 OK 12.3 23.4 ALL OK Sensitivity: 20.4(db) DoppRMS: 1.78(Hz) Details of the error This is an error when communication with DRAGON is not established. Communication error due to a hardware problem could be the cause. It is highly possible that the hardware on the DRAGON side is defective. Time out error for response to BIOS call. Communication error due to a hardware problem could be the cause. It is highly possible that the hardware on the DRAGON side is defective. Displayed message No connection to DRAGON Command error www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 217 5 6 7 8 5 6 7 8 C D F A B E 12. GPS information • ”Position information” will be displayed when the cursor is at the “Position” position and the [CR] key is pressed on the remote controller. • “Status information” will be displayed when the cursor is at the “Sv Stat” position and the [CR] key is pressed on the remote controller. • “Diagnosis information” will be displayed when the cursor is at the “Ver&Diag” position and the [CR] key is pressed on the remote controller. • “Error information” will be displayed when the cursor is at the “Err Info” position and the [CR] key is pressed on the remote controller. • When an inspection is performed, “status information” (the screen shown above) will be displayed first. 13. Voice play back • Voice file (WAVE format) will be played back. • The voice selected by the [CR] key on the remote controller will be played back. • Volume level can be changed by the [ ] and [ ] keys on the remote controller. 12. GPS information 0D T2 H25.5 V25.5 01/03/28 23:05:47 Position Sv Stat Ver & Diag Err Info SV 10 26 18 23 17 9 14 4 Azi 119 25 310 305 317 196 260 142 Ev 39 60 25 33 49 56 73 81 SNR 3.0 4.9 0.0 0.0 0.0 0.0 0.0 0.0 Flag UY-- UYC- ---m ---m ---m ---m ---m ---m Acc 3 2 f f f f f 3 Doppler -2249 -1051 +0 +0 +0 +0 +0 +0 SrchW 2883 3496 12487 21812 21812 21812 5994 5994 13. Sound play ADPCM fixation 11K 1K L ADPCM fixation 11K 1K mono ADPCM fixation 11K 1K R ADPCM fixation 11K 1K ste ADPCM fixation 19K 1K L ADPCM fixation 19K 1K mono ADPCM fixation 19K 1K R Main fader Vol.[0-15] 6 [-> Vol up, <- Vol down] [return] It returns to a menu screen. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 218 1 2 3 4 1 2 3 4 C D F A B E 14. File maintenance • File can be copied, deleted or dumped. Refer to HELP for “how to use” each function. 15. Picture check MENU A pattern is selected by the [ ] and [ ] keys and an image is displayed by the [CR] key. 1. Plain …Display is made in the order of black, blue, red, pink, green, light blue, yellow and white by the [ ] and [ ] keys operation on the remote controller. 2. Color bar …White, yellow, light blue, green, pink, red, blue, black bars will be displayed from left to right. 3. Cross hatch 4. Sweep 5. Step 6. Lamp 7. Window 8. Mono scope 9. Cycle line 1 10. Cycle line 2 11. Horizontal stripe 1 12. Horizontal stripe 2 13. Chinese character pattern 14. Map (map.jpg) 15. Natural image (nature.jpg) 16. Portrait 1 (hito1.jpg) 17. Portrait 2 (hito2.jpg) 14. File maintenance Totale Capacity : 216.5K Remain : 216.3K Media:SRAM: Path: LOGINFO.CFG 20 LOCPOS .DAT 20 84 02 / 08 / 07 17:35 68 01 / 01 / 01 21:22 [1]Media [2]Copy [3]Delete [4]Dump [0]Help 15. Picture check MENU 1/2 1. Plane 2. Color Bar 3. Cross Hatch 4. Sweep 5. Step 6. Ramp 7. Window 8. Mono Scope 9. Vertical Resolution Column [Push OK to make a selection] [return] It returns to a menu screen. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 219 5 6 7 8 5 6 7 8 C D F A B E 16. Device Check • The device inspection above is performed only for engineering. • (Device selection) Select a device with the [ ] and [ ] keys on the main unit, and decide with the [CR] key. • (Pattern selection) Select a pattern with the [ ] and [ ] keys on the main unit, and start the inspection with the [CR] key. * Only when ASIC is selected, the bit shift pattern can be selected. Return to the device selection screen with the [RETURN] key on the main unit. • (During the inspection) Stop the inspection with the [RETURN] key on the main unit, and return to the device selection screen. 17. All memory clear (for Service) • SRAM (application domain) is cleared. • FLASH (application domain) is cleared. • If SRAM clear is not successful, FLASH will not be cleared. • After the inspection screen is displayed, the above process is executed by the [NAVI] key on the remote controller. • The result of the process is displayed. 16. Device Check 1. SDRAM (0X48000000 - 0X4BFFFFFF) 2. SRAM (0X42000000 - 0X4203FFFF) 3. ASIC (0X43000270 - 0X43000274) 4. ALL Device [return] It returns to a menu screen. 17. All memory clear (for Service) The clearance of SRAM (application domain) The clearance of FLASH (application domain) [NAVI] Inspection is performed. [return] It returns to a menu screen. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 220 1 2 3 4 1 2 3 4 C D F A B E 18. Initialization of a backup variable • Back up variables are initialized by the [NAVI] key on the remote controller for system reset. • The screen will return to the menu screen by the [RETURN] key on the remote controller. 18. Initialization of a backup variable A backup variable is initialized. Cautions System reset is carried out after initialization. [NAVI] A backup variable is initialized. [return] It returns to a menu screen. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 221 5 6 7 8 5 6 7 8 C D F A B E 7. GENERAL INFORMATION 7.1 DIAGNOSIS 7.1.1 DISASSEMBLY - Preparation for Removing the Grille Assy - Removing the Case (not shown) 1. Remove the two screws and then remove the Case. To remove the Grille Assy block, it must always be moved to the OPEN position. 1. Rotate the gear using a screwdriver, etc. (ø2.8 or smaller) from the slit on the bottom surface of the main unit (Fig.1) in the direction of the arrow, and move the Grille Assy to OPEN position. Note) Though the gear is heavy, please turn carefully not to inflict too much force. Turning with excessive force may cause damage in the rack or gear in the driving section. Fig.1 FRONT www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 222 1 2 3 4 1 2 3 4 C D F A B E - Removing the Monitor Assy 1 Fig.3 1 Remove the two screws. (Fig.2) (2) Remove the screw to remove the Cover. Do not pull the connecting flexible cable. (Fig.3) (3) Remove the flexible cable from the connector to remove the Monitor Assy. Push the lid of the c up with the top of precision screwdriver (minu and then remove the flexible cable. Take much not to pull the connector forcedly or break it o because it is easy to be damaged. And also, u precision screwdriver in the same way in the installation. (Fig.3) Fig.2 ver www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 223 5 6 7 8 5 6 7 8 C D F A B E 1 Fig.4 - Removing the Case Unit (Fig.4) Guide 3 3 3 Fig.6 CD Mechanism Module - Removing the Monitor PCB (Fig.5) Remove the five screws. 1 Remove the two screws and then remove the Guide. 3 Remove the five screws and then remove the Case Unit. 2 2 1 1 1 3 2 2 1 1 Case Unit Remove the four screws. 2 1 Monitor PCB Fig.5 Disconnect the connector and then remove the Monitor PCB. 1 1 1 - Removing the CD Mechanism Module (Fig.6) Remove the four screws. 1 1 3 1 Disconnect the connector and then remove the CD Mechanism Module. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 224 1 2 3 4 1 2 3 4 C D F A B E Fig.7 Panel Unit 1 1 - Removing the Panel Unit (Fig.7) Remove the two screws. 1 2 2 2 2 Fig.8 Heat Sink 2 2 - Removing the Heat Sink (Fig.8) Remove the two screws. 1 2 2 2 2 2 1 1 Remove the seven screws and then remove the Heat Sink. 2 Remove the four screws. 2 Disconnect the connector and then remove the Panel Unit. - Removing the System Unit (Fig.9) Fig.9 Remove the six screws. 1 System Unit 1 1 1 1 1 1 Disconnect the connector and then remove the System Unit. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 225 5 6 7 8 5 6 7 8 C D F A B E - Removing the Chassis Unit (Fig.10) 1 Fig.10 Chassis Unit Fig.11 - Removing the DVD Mechanism Module (Fig.11) Remove the three screws and then remove the Chassis Unit. 1 1 1 1 DVD Mechanism Module 1 Remove the four screws and then remove the DVD Mechanism Module. 1 1 1 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 226 1 2 3 4 1 2 3 4 C D F A B E - Removing the CC Unit (Fig.12) Fig.12 2 2 Fig.13 - Removing the Connector Unit (Fig.13) 1 2 1 2 CC Unit Straighten the tab at location indicated. 1 Remove the four screws. 2 2 2 1 Disconnect the connector and then remove the CC Unit. Connector Unit Remove the two screws. 1 Disconnect the connector and then remove the Connector Unit. 3 Main PCB Unit - Removing the Main PCB Unit (Fig.13) Straighten the two tabs at locations indicated. 2 Remove the screw. 3 Disconnect the connector and then remove the Main PCB Unit. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 227 5 6 7 8 5 6 7 8 C D F A B E - Precautions on handling the mechanism module 1. Hold the upper and main frames. 2. Do not hold the front portion of the upper frame. It is a delicate part. 3. Do not touch the switches on the top panel. 4. Be careful not to catch the flexible cables. Do not touch here. Do not touch here. Do not hold this delicate portion. - Removing the module pc board Load motor leads and clamp SW leads Connector (for 8/12 detection flexible cable) Connector (for pickup flexible cable) Connector (for CRG flexible cable) Short here. A B C Module pc board 1. Set the mechanism to the lock position (disc load standby position). 2. Place the mechanism module upside down. 3. Short the two lands on the pickup flexible cable as shown below. 4. Be sure to disconnect the pickup flexible cable and the CRG flexible cable from the connectors to protect them from damages. 5. Remove solder from the load motor leads and clamp SW leads. 6. Loosen the two fixing screws. Lift the position A of the module pc board lightly and move it in the direction B to remove it. Be careful not to damage the flexible cable C. 7. Disconnect the 8/12 detection flexible-cable from the connector. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 228 1 2 3 4 1 2 3 4 C D F A B E - Removing the pickup unit 1. Remove the module pc board in accordance with the procedure of "Removing the module pc board.” 2. While holding the pickup case, remove the skew screw (main). 3. Lifting the end of the pickup rack, slide the main shaft, and remove the pickup unit. Notes: Replacing the pickup unit requires the skew adjustment. Remove glue from both ends of the main and sub shafts, and skew stud. Do not reuse the old skew screw. Be sure to use a brand-new skew screw supplied with a new pickup unit. Fix the skew screw with glue (GYL1001) after adjustment. Sub shaft Pickup unit Skew screw Skew screw (main) Skew screw www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 229 5 6 7 8 5 6 7 8 C D F A B E - How to hold the Mechanism Unit 1. Hold the top and bottom frame. 2. Do not squeeze top frame's front portion too tight, because it is fragile. - Removing the Upper and Lower Frames 1. With a disc clamped, remove the four springs (A), the two springs (B), the two springs (C), and the four screws. 2. To remove the upper frame, open it on the fulcrum A. 3. While lifting the carriage mechanism, remove the three dampers. 4. With the frames removed, insert the connectors coming from the main unit and eject the disc. Caution: Before installing the carriage mechanism in the frames, be sure to apply some alcohol to the dampers and set the mechanism to the clamp mode. Do not squeeze. Lower Frame Damper Carriage Mechanism A C A B B Damper Damper C A A A Upper Frame www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 230 1 2 3 4 1 2 3 4 C D F A B E - Removing the Pickup Unit 1. Apply shorting solder to the Pickup flexible cable. Disconnect the cable. 2. Set the mechanism to the clamp mode. 3. Remove the lead wires from the inner holder. 4. Remove the washer, styling holder, change arm, and pickup lock arm. 5. While releasing from the hook of the inner holder, lift the end of the feed screw. Caution: In assembling, move the planet gear to the load/eject position before setting the feed screw in the inner holder. Shorting Solder Planet Gear Change Arm Inner Holder Styling Holder Feed Screw Washer Pickup Lock Arm www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 231 5 6 7 8 5 6 7 8 C D F A B E 7.1.2 PCB LOCATIONS GPS UNIT B MAIN PCB UNIT L CONNECTOR UNIT K CC UNIT A SYSTEM UNIT G PANEL PCB J KEYBOARD PCB I MONITOR PCB H DVD CORE UNIT(MS3R) C COMPOUND UNIT(A) D COMPOUND UNIT(B) E CD CORE UNIT(S10.1) F www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 232 1 2 3 4 1 2 3 4 C D F A B E 7.1.3 CONNECTOR FUNCTION DESCRIPTION 1. BUS+ 2. IPGND 3. IPGND 4. MUTE 5. BUS- 1 2 3 4 5 6 7 8 9 10 11 6. IPGND 7. Lch 8. ASEN 9. Rch 10. GND 11. GND IP-BUS 10 8 6 4 2 9 7 5 3 1 EXTERNAL 1. NC 2. NC 3. GNDD 4. CTOEX 5. EXTOC 6. HYOKA 7. CTOTA 8. TATOC 9. VTA 10. GND 16 14 12 10 8 6 4 2 15 13 11 9 7 5 3 1 1. RR+ 2. FR+ 3. RR- 4. FR- 5. RL+ 6. FL+ 7. RL- 8. FL- 9. SPEED PULSE 10. SYSTEM REMOTE 11. PARKING BRAKE 12. A. ANT 13. ACC 14. REVERSE SIGNAL 15. ILM 16. MUTE 17. B. UP 18. GND 19. OPEN ONLY 20. GND 20 18 19 17 POWER SUPPLY 16 14 12 10 8 6 4 2 15 13 11 9 7 5 3 1 1. REAR MONI GND 2. REAR MONI OUTPUT 3. NC 4. NC 5. BACK CAMERA GND 6. BACK CAMERA INPUT 7. VIDEO GND 8. VIDEO INPUT 9. AUDIO INPUT Lch GND 10. AUDIO INPUT Lch 11. AUDIO INPUT Rch GND 12. AUDIO INPUT Rch 13. GNDA 14. SUBWOOFER OUT Lch 15. GNDA 16. SUBWOOFER OUT Rch 17. GNDA 18. REAR OUTPUT Lch 19. GNDA 20. REAR OUTPUT Rch 21. GNDA 22. FRONT OUTPUT Lch 23. GNDA 24. FRONT OUTPUT Rch 20 18 19 17 AV 24 22 23 21 AV-BUS 1 2 3 4 5 6 7 9 8 10 11 12 13 1. VIDEO GND 2. COMP VIDEO 3. NC 4. IP-SEL1 5. IP-SEL2 6. LED-V 7. GND 8. BEEP MUTE 9. BEEP- 10. REMOUT 11. NEW AV SENS 12. AV ON 13. BEEP+ GPS ANTENNA ANTENNA WIRED REMOTE CONTROL www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 233 5 6 7 8 5 6 7 8 C D F A B E 7.2 IC * K4S561632E-TL75 DQ0 2 VDDQ 3 DQ1 4 DQ2 5 VSSQ 6 DQ3 7 DQ4 8 VDDQ 9 DQ5 10 DQ6 11 VSSQ 12 DQ7 13 VDD 14 WE 15 CAS 16 RAS 17 CS 18 BA1 19 A10/AP 20 A0 21 A1 22 A2 23 A3 24 48 DQ14 47 VSSQ 46 DQ13 45 DQ12 44 VDDQ 43 DQ11 42 DQ10 41 VSSQ 40 DQ9 39 DQ8 38 37 VSS 36 UDQM 35 CLK 34 CKE 33 NC 32 A9 31 A8 30 A7 29 A6 28 A5 54 A4 53 VSS VDD 1 VDD 25 49 DQ15 50 VSS 26 27 52 51 LDQM BA0 A11 NC VDDQ A0-A11 : Address input BA0-BA1 : Bank select address DQ0-DQ15 : Data input/output CLK : Clock input CKE : Clock enable cs : Chip select ras : Row address strobe cas : Column address strobe we : Write enable LDQM : Lower DQ mask enable UDQM : Upper DQ mask enable VDD : Power supply VSS : GND VDDQ : Data output power supply VSSQ : Data output GND NC : Not used * HY57V561620CLT-H DQ0 2 VDDQ 3 DQ1 4 DQ2 5 VSSQ 6 DQ3 7 DQ4 8 VDDQ 9 DQ5 10 DQ6 11 VSSQ 12 DQ7 13 VDD 14 WE 15 CAS 16 RAS 17 CS 18 BA1 19 A10/AP 20 A0 21 A1 22 A2 23 A3 24 48 DQ14 47 VSSQ 46 DQ13 45 DQ12 44 VDDQ 43 DQ11 42 DQ10 41 VSSQ 40 DQ9 39 DQ8 38 37 VSS 36 UDQM 35 CLK 34 CKE 33 NC 32 A9 31 A8 30 A7 29 A6 28 A5 54 A4 53 VSS VDD 1 VDD 25 49 DQ15 50 VSS 26 27 52 51 LDQM BA0 A11 NC VDDQ A0-A11 : Address input BA0-BA1 : Bank select address DQ0-DQ15 : Data input/output CLK : Clock input CKE : Clock enable cs : Chip select ras : Row address strobe cas : Column address strobe we : Write enable LDQM : Lower DQ mask enable UDQM : Upper DQ mask enable VDD : Power supply VSS : GND VDDQ : Data output power supply VSSQ : Data output GND NC : Not used IC's marked by * are MOS type. Be careful in handling them because they are very liable to be damaged by electrostatic induction. K4S561632E-TL75 HY57V561620CLT-H UPD705103GM-180S1 TC74LCX08FTS1 TC7SH04FUS1 PD6336C PEH007A PEH008A TC74LCX245FTS1 TC74LCX541FTS1 TC7SH00FUS1 TC7SH08FUS1 UPD4721GSS1 AK4351VT MB86291APFVS-G-DL TC7SH14FUS1 BH7236AF UPB1027GS PD3390A ADC12H034CIMSAS1 PD6519A PE5479A OZ961ISN S-29221BR0I-J8T1 TPS850 BD6171KV PE5478A TC74VHCT08AFTS1 NJM2561F1 TA2050FS1 BA5835FP NJM2885DL1-33 PE5454B UPD63763GJ PE5430A www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 234 1 2 3 4 1 2 3 4 C D F A B E A1-A23 : Address Bus bcyst : Bus Cycle Start BT16B : Boot Bus Size 16-bit cas : Column Address Strobe CKE : Clock Enable CLKOUT : Clock Out CMODE : Clock Mode cs)-cs& : Chip Select D0-D31 : Data Bus DCK : Debug Clock DDI : Debug Data Input DDO : Debug Data Output DMAAK0-DMAAK3 : DMA Acknowledge DMARQ0-DMARQ3 DMA Request DMS : Debug Mode Select drst : Debug Reset GND_I : Ground GND_O : Ground GND_PLL : Ground hldak : Hold Acknowledge hldrq : Hold Request IC1 : Internally Connected INTP00-INTP03,INTP10-INTP13 : Interrupt Request From Peripheral iord : I/O Read iowr : I/O Write llben : Lower Lower Byte Enable LLDQM : Lower Lower DQ Mask Enable luben : Lower Upper Byte Enable LUDQM : Lower Upper DQ Mask Enable mrd : Memory Read mwr : Memory Write Strobe nmi : Non-Maskable Interrupt Request PORT0-PORT4,PORTA0-PORTA7 : Port R/w : Bus Read or Write Status ras : Row Address Strobe ready : Ready reset : Reset RXD : Receive Data sclk : Serial Clock SDCLKOUT : SDRAM CLKOUT SI : Serial Input SO : Serial Output stopak : Stop Acknowledge tc : Terminal Count TCLR : Timer Clear TI : Timer Input TO10,TO11 : Timer Output TRCDATA0-TRCDATA3 : Trace Data TXD : Transmit Data ulben : Upper Lower Byte Enable ULDQM : Upper Lower DQ Mask Enable uuben : Upper Lower Byte Enable UUDQM : Upper Upper DQ Mask Enable VDD_I : Power Supply VDD_O : Power Supply VDD_PLL : PLL Power Supply we : Write Enable X1,X2 : Crystal Oscillator * UPD705103GM-180S1 6 4 1 3 2 7 5 9 11 14 12 13 8 10 VCC 4B 4A 3B 3A 3Y 1A 1B 1Y 2A 2B 2Y GND 4Y * TC74LCX08FTS1 1 NC 2 IN A 3 GND 4 OUT Y 5 VCC * TC7SH04FUS1 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 235 5 6 7 8 5 6 7 8 C D F A B E 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 84 85 86 87 88 89 90 91 92 93 94 95 96 97 98 99 100 101 102 103 104 23 83 160 161 162 163 164 165 166 167 168 169 170 171 172 173 174 175 176 177 178 105 24 82 159 228 229 230 231 232 233 234 235 236 237 238 239 240 241 242 243 244 179 106 25 81 158 227 288 245 180 107 26 80 157 226 287 246 181 108 27 79 156 225 286 247 182 109 28 78 155 224 285 248 183 110 29 77 154 223 284 249 184 111 30 76 153 222 283 250 185 112 31 75 152 221 282 251 186 113 32 74 151 220 281 252 187 114 33 73 150 219 280 253 188 115 34 72 149 218 279 254 189 116 35 71 148 217 278 255 190 117 36 70 147 216 277 256 191 118 37 69 146 215 276 257 192 119 38 68 145 214 275 258 193 120 39 67 144 213 274 273 272 271 270 269 268 267 266 265 264 263 262 261 260 259 194 121 40 66 143 212 211 210 209 208 207 206 205 204 203 202 201 200 199 198 197 196 195 122 41 65 142 141 140 139 138 137 136 135 134 133 132 131 130 129 128 127 126 125 124 123 42 64 63 62 61 60 59 58 57 56 55 54 53 52 51 50 49 48 47 46 45 44 43 VSS PIO29 USBXPWREN USBXOVRCUR UVD1M UVD1P UVD2M UVD2P USBOVRCUR USB_CLK XCS_SRAM XWR_SRAM PIO31 IR_RX TEST0 XTAL0 MST EXTAL0 UART9_TXD UART8_TXD UART7_TXD VSS PIO27 PIO28 XCS_FLASH D0 XMRD USBPWREN XIOWR NC NC NC XREADY SRAM_CSSEL PIO30 XCS6 XTST SMCK XSM GDC_WT UART9_RXD UART8_RXD UART7_RXD UART6_TXD DSP_BCLKI PIO26 D2 D1 XMWR XLLBEN XIORD NC NC NC XBCYST XCS2 XCS3 DREQ0 DREQ1 INT3 INT2 INT0 ATA_DA0 ATA_DA1 UART6_RXD UART5_RXD PIO25 D4 D3 VSS VSS XLUBEN VDD NC VSS NC VDD VDD XCS5 VSS DREQ2 VDD INT1 VDD VSS ATA_INT OVSS0 UART5_TXD PIO24 D6 D5 VDD VSS ATA_XDMACK UART4_RXD UART4_TXD PIO22 OVSS7 D8 D7 ATA_XDIOR ATA_IORDY XRESET UART3_TXD OVDD3 D10 D9 VDD VDD ATA_DMARQ ATA_XDIOW OVDD0 DSP_BDI XCS_DSP D12 D11 ATA_DD1 ATA_DD0 UART3_RXD UART2_TXD DSP_XHINT PIO23 D16 D15 VSS ATA_DD3 ATA_DD2 UART2_RXD DSP_HRDY D18 D17 VDD ATA_DD5 ATA_DD4 UART1_RXD UART1_TXD OVSS6 D20 D19 VDD VDD ATA_DD7 ATA_DD6 A23 DSP_BFSO DSP_BDO D22 D21 VDD ATA_DD8 ATA_XRESET CPU_CLK DSP_BCLKO D24 D23 VSS ATA_DD10 ATA_DD9 UART_XDCD OVSS1 XCS_SRAMH PIO_OUT D26 D25 VSS ATA_DD12 ATA_DD11 UART1_XCTS OVDD2 OVSS5 D27 VDD ATA_DD14 ATA_DD13 UART_XRI UART_XDSR DSP_BFSI D14 D13 VSS VDD ATA_DA2 ATA_DD15 OVDD1 DSP_XRS TEST1 D29 D28 ATA_XCS0 ATA_XCS1 UART1_XDTR UART1_XRTS DSP_ATTCNT CD_LRCLK D30 VSS VDD PC_XPWR ATA_DIR PIO0 D31 CD_BLK A2 VSS VDD VPDP VDD A11 VSS PC_XVS2 VDD VDD PC_BVD1 VSS PC_XCD1 VDD PC_XOE VSS VSS PC_XUBUF PC_XLBUF PIO1 CD_MCLK ADC_GCNT0 A3 A4 A5 A7 A9 A12 PC_READY PC_RESET PC_WXT PC_BVD2 PC_WP PC_XCD2 PC_XCE1 PC_XCE2 PC_XVS1 PC_XIORD PC_XIOWR PC_XWE PIO2 OVSS2 ADC_GCNT2 ADC_GCNT1 ADC_BCLK ADC_MCLK A6 A8 A10 TEST2 DAC_MCLK DAC_BCLK PC_XREG PC_A0 PIO20 PIO19 PIO17 PIO15 PIO13 PIO11 PIO9 PIO7 PIO5 PIO3 VSS ADC_DATA ADC_LRCLK TEST4 EXTAL1 OVSS4 XTAL1 TEST3 DAC_LRCLK DAC_DATA PIO21 OVSS3 CD_DATA PIO18 PIO16 PIO14 PIO12 PIO10 PIO8 PIO6 PIO4 VSS TOP VEIW TOP VEIW * PD6336C - Pin Arrangement Chart www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 236 1 2 3 4 1 2 3 4 C D F A B E A2-A11,A23 D0-D31 CPU_CLK XBCYST XRESET XCS2(SRAM) XCS3(ASIC) XCS5(PCCARD) XCS6(DSP) XIOWR XIORD XMWR XMRD XLLBEN XLUBEN DMARQ0 DMARQ1 DMARQ2 INTP0 INTP1 XREADY INTP2 INTP3 SRAM_CSSEL XCS_SRAM XCS_SRAMH XCS_FLASH XCS_DSP XWR_SRAM CPU I/F BLOCK TOP SECTION DMA CHANNEL SELECT SECTION WAIT CONTROL SECTION INTERRUPT CONTROL SECTION PROTECT and CHIP SELECT GENERATOR SECTION TIMER SECTION ASIC ASIC_CLK XRESET A7-A2 WExx RExx DMAxx WAIT WTxx INTxx DMA INT AUDIO BLOCK CD-ROM BLOCK PERI BLOCK (SIO,PIO, REMOTE CONTROL) ATAPI BLOCK PC-CARD BLOCK SOUND BLOCK USB BLOCK CPU - Block Diagram Chart www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 237 5 6 7 8 5 6 7 8 C D F A B E 1 A15 2 A14 3 A13 4 A12 5 A11 6 A10 7 A9 8 A8 11 WE 12 RESET 13 NC 14 NC 15 16 RY/BY A18 A0-A18,A-1 RY/BY BYTE OE DQ0-DQ15 :Address input :Ready/busy output :8bit,16bit mode select :Output enable :Data input/output WE :Write enable CE :Chip enable RESET:Reset 9 NC 10 NC 17 A17 18 A7 19 A6 20 A5 21 A4 22 A3 23 A2 24 A1 A16 BYTE VSS DQ15/A-1 DQ7 DQ14 DQ6 DQ13 38 DQ4 37 VCC 36 DQ11 35 DQ3 34 33 DQ10 DQ2 DQ5 39 DQ12 32 DQ9 31 DQ1 30 DQ8 29 DQ0 28 OE 27 VSS 26 CE 25 A0 47 46 45 44 43 42 48 41 40 * PEH007A 1 A15 2 A14 3 A13 4 A12 5 A11 6 A10 7 A9 8 A8 11 WE 12 RESET 13 NC 14 NC 15 16 RY/BY A18 A0-A18,A-1 RY/BY BYTE OE DQ0-DQ15 :Address input :Ready/busy output :8bit,16bit mode select :Output enable :Data input/output WE :Write enable CE :Chip enable RESET:Reset 9 NC 10 NC 17 A17 18 A7 19 A6 20 A5 21 A4 22 A3 23 A2 24 A1 A16 BYTE VSS DQ15/A-1 DQ7 DQ14 DQ6 DQ13 38 DQ4 37 VCC 36 DQ11 35 DQ3 34 33 DQ10 DQ2 DQ5 39 DQ12 32 DQ9 31 DQ1 30 DQ8 29 DQ0 28 OE 27 VSS 26 CE 25 A0 47 46 45 44 43 42 48 41 40 * PEH008A 14 B5 13 B6 12 B7 11 B8 10 GND 9 A8 8 A7 1 DIR 2 A1 3 A2 4 A3 5 A4 6 A5 7 A6 15 B4 16 B3 17 B2 18 B1 19 oe 20 VCC * TC74LCX245FTS1 1 2 3 4 5 6 7 8 9 10 20 19 18 17 16 15 14 13 12 11 OE1 A1 A2 A3 A4 A5 A5 A6 A7 A8 GND VCC OE2 Y1 Y2 Y3 Y4 Y5 Y6 Y7 Y8 * TC74LCX541FTS1 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 238 1 2 3 4 1 2 3 4 C D F A B E * TC7SH00FUS1 * TC7SH08FUS1 1 IN B 2 IN A 3 GND 4 OUT 5 VCC 1 IN B 2 IN A 3 GND 4 OUT Y 5 VCC 1 DIF1 LRCK SDATA BICK pd MCLK DEM CKS 2 3 4 5 6 7 8 DIF0 VSS VREF VDD VCOM AOUTL AOUTR TST 16 15 14 13 12 11 10 9 CKS LRCK Clock Divider BICK SDATA Serial Input Interface MCLK DEM PD TST VREF ∆Σ Modulator AOUTL 8X Interpolator LPF ∆Σ Modulator AOUTR 8X Interpolator LPF VDD VSS VCOM De-emphasis Control DIF1 DIF0 AK4351VT VDD C1+ VCC C5+ DIN2 C5- C4+ GND C4- STBY DOUT2 VCHA 20 18 19 17 14 15 16 13 1 3 2 4 7 6 5 8 C1- DIN1 DOUT1 VSS ROUT2 RIN2 12 11 9 10 ROUT1 RIN1 UPD4721GSS1 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 239 5 6 7 8 5 6 7 8 C D F A B E Host Interface Memory Interface Controller External Video Interface Controller Display Controller DAC Set-up Engine 2D/3D Rendering Engine Embedded SDRAM (64bit x 256K word) 64bit D0-32 A2-24 ARGB DRGB RBT656 * MB86291APFVS-G-DL 1 NC 2 IN A 3 GND 4 OUT Y 5 VCC * TC7SH14FUS1 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 240 1 2 3 4 1 2 3 4 C D F A B E 24 23 22 21 20 19 18 17 16 15 14 13 1 2 3 4 5 6 7 8 9 10 11 12 CLAMP 75Ω SYNC CLAMP 75Ω SYNC CLAMP 75Ω SYNC MATRIX FILTER PHASE SHIFTER F . F BPF DELAY Y/C MIX SYNC MIX B-Y MOD. R-Y MOD. BFP GEN. 75Ω 75Ω 75Ω SYNC BFP BFP GND1 RIN GIN BIN NC SCIN NT/PAL BFPOUT NC SYNCIN SYNCOUT VCC1 NC NC COUT YOUT YTRAP NC VCC2 VOUT BOUT ROUT GOUT GND2 BH7236AF 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 PD 25 2 4 2 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 IF-MIXin GND (IF-MIX) RF-MIXout VCC (RF-MIX) RF-MIXin VCC (1stLO-OSC) 1stLO-OSC1 1stLO-OSC2 GND (1stLO-OSC) VCC (phase detector) PD-Vout3 PD-Vout2 PD-Vout1 GND (phase detector) GND (RF-MIX) VCC (IF-MIX) VGC (IF-MIX) IF-MIXout GND (2ndIF-AMP) 2ndIFin1 2ndIFin2 2ndIFbypass VCC (2ndIF-AMP) 2ndIFout REFout VCC (reference block) REFin GND (divider block) LOout VCC (divider block) UPB1027GS www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 241 5 6 7 8 5 6 7 8 C D F A B E Pin No. Pin Name I/O Format Function and Operation 1 VCC0 Power supply (3.3V) 2 VSS0 GND 3 TXD2 l/O SIO2 Transmission data input / output 4 RXD2 l/O SIO2 Reception data input / output 5 TXD1 O C SIO1 Transmission data output 6 RXD1 l SIO1 Reception data input 7 TXD0 O C SIO0 Transmission data output 8 RXD0 l SIO0 Reception data input 9 SPEED l SP I/F input 10 ADCSB O C AD I/F output 11 ADSCK O C AD I/F output 12 ADTXD O C AD I/F output 13 ADRXD l AD I/F input 14 ADSRX l AD I/F input 15 ADIO0 l/O AD I/F input / output 16 ADIO1 l/O AD I/F input / output 17 ADIO2 l/O AD I/F input / output 18 VCC1 Power supply (3.3V) 19 VSS1 GND 20 PWM O PWM signal output 21 PLINT l PLL I/F input 22 PLCE O C PLL I/F output 23 PLSCK O C PLL I/F output 24 PLTX O C PLL I/F output 25 PLRX l PLL I/F input 26 PLIO0 l/O PLL I/F input / output 27 PLIO1 l/O PLL I/F input / output 28 PLIO2 l/O PLL I/F input / output 29 DDINT l Darc I/F input 30 DDCE O C Darc I/F output 31 DDSCK O C Darc I/F output 32 DDTX O C Darc I/F output 33 DDRX l Darc I/F input 34 DDIO0 l/O Darc I/F input / output 35 DDIO1 l/O Darc I/F input / output 36 DDIO2 l/O Darc I/F input / output 37 TIOA0 l/O ParaIIeI input / output 38 TIOA1 l/O ParaIIeI input / output 39 TIOB0 l/O ParaIIeI input / output 40 TIOB1 l/O ParaIIeI input / output 41 VCC2 Power supply (3.3V) 42 VSS2 GND 43-53 A19-9 l/O Address bus input / output 54 VCC3 Power supply (3.3V) 55 VSS3 GND 56-64 A8-0 l/O Address bus input / output 65 VCC4 Power supply (3.3V) 66 VSS4 GND 67-82 D0-15 l/O Address bus input / output 83 VCC5 Power supply (3.3V) 84 VSS5 GND 85 WRHB l/O Upper data write strobe input / output 86 WRLB l/O Lower data write strobe input / output 87 RDB l/O Read data strobe input / output 88 CS2B l/O Chip select aria 1 for external storage input / output 89 90 CS0B l/O Chip select aria 0 for ROM input / output VCC6 Power supply (3.3V) -Pin Functions(PD3390A) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 242 1 2 3 4 1 2 3 4 C D F A B E Pin No. Pin Name I/O Format Function and Operation 91 VSS6 GND 92 TEST2 Test mode 93 CKOEB l CK output enable input 94 CK O CPU clock output 95 CS5B O C DRAM low address strobe output 96 CS3B O O DRAM column address strobe output 97 CS1B C DRAM column address upper byte strobe output 98 RTCVSS1 l Power supply (3.3V) 99 SRAMB l Backup memory select input 100 STANBYB Stand by signal input 101 RTCVSS0 GND 102 XRTCIN l C C C Sub crystal oscillator input (RTC) 103 XRTCOUT O Sub crystal oscillator output (RTC) 104 RTCVCC Power supply (3.3V) 105 PCKSEL0 l Processor clock select input 106 PCKSEL1 l Processor clock select input 107 CCKSEL l l/O CRCK signal select input 108 CCKDIR Carrier clock direct input / inverter amp output Power supply (3.3V) 109 CCKVCC 110 CRCK l Carrier clock input 111 CCKGND GND 112-118 PC0-6 l/O Parallel input / output 119 NMI Connect to VCC 120 RESETB l System reset input 121 MSTRSTB l Test reset input 122 TEST0 l Test mode input 123 TEST1 l Test mode input 124 REFSEL l GPS reference clock select input 125 REFCK l Reference clock input 126 VCC7 Power supply (3.3V) 127 VSS7 GND 128 XAUXIN l C C Sub crystal oscillator output input (AUX) 129 XAUXOUT O Sub crystal oscillator output (AUX) 130-133 PIN0-3 l Parallel input 134-137 PIO4-7 l/O Parallel input / output 138 TXD3 l/O SIO3 Transmission data input / output 139 RXD3 l/O SIO3 Reception data input / output 140 BOWWOWB O Watch dog timer output 141 IFDIR l/O IF direct input / IF inverter amp output 142 IFVCC l l Power supply (3.3V) 143 IF IF input IF amp GND input Format C Meaning CMOS 144 * PD3390A 72 37 109 144 36 1 73 108 IFGND www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 243 5 6 7 8 5 6 7 8 C D F A B E ADC12H034CIMSAS1 Address Latch and Decoder Control Timing Analog Input Multiplexer SAR +Main DAC -Main DAC -Correction DAC +Correction DAC Output Shift Register ALU RAM Output Select Logic and Buffer 1 CH0 2 CH1 3 CH2 4 CH3 5 COM 6 MUX OUT1 7 A/DIN1 8 MUX OUT2 9 A/DIN2 10 VREF- 11 VREF+ 12 DGND 24 VD+ 23 DOR 22 CCLK 21 SCLK 20 DI 19 DO 18 CS 17 CONV 16 EOC 15 PD 14 AGND 13 VA+ A15 1 A14 2 A13 3 A12 4 A11 5 A10 6 A9 7 A8 8 N.C. 9 N.C. 10 WE 11 RESET 12 N.C. 13 N.C. 14 RY/BY 15 N.C. 16 A17 17 A7 18 A6 19 A5 20 A4 21 A3 22 A2 23 A1 24 48 A16 47 BYTE 46 VSS 45 DQ15/A-1 44 DQ7 43 DQ14 42 DQ6 41 DQ13 40 DQ5 39 DQ12 38 DQ4 37 VCC 36 DQ11 35 DQ3 34 DQ10 33 DQ2 32 DQ9 31 DQ1 30 DQ8 29 DQ0 28 OE 27 VSS 26 CE 25 A0 CIRCUIT WRITE WRITE/ERASE PULSE TIMER RY/BY BUFFER CONTROL (COMMAND LOW VCC LATCH DECODER Y YGATE 4,194,304 CELL MATRIX DATA INPUT/OUTPUT BUFFER CHIP ENABLE CIRCUIT OUTPUT ENABLE STB STB ADDRESS X DECODER LATCH DETECT CIRCUIT CIRCUIT REGISTER) CIRCUIT ERASE A-1 * PD6519A www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 244 1 2 3 4 1 2 3 4 C D F A B E Pin No. Pin Name I/O l l l O Function and Operation 1 PNLADX X directions analog input 2 LSEN Lens sense input 3 PNLADY Y directions analog input 4 AVSS A/D converter GND 5 DIMMER Dimmer anarog output 6 INVBST_DA Back light boost signal output (low temperature) 7 AVREF1 l D/A converter reference voltage 8 RXD Data input from system microcomputer (UART) 9 TXD O Data output to system microcomputer (UART) 10 MFLPW O Back light control output 11 LKYDT I O Data input from LCD micro computer (UART) 12 LDPDT Data output to LCD micro computer (UART) 13 MVIPW O Picture power supply control output 14 OSDCS O OSD chip select output 15 NC Not used 16 TSI l O l l Test program data input 17 TSO Test program data output 18 TSCK Test program clock input 19 OVICHK Back light power supply overcurrent detect input 20 EPRRST l EEPROM reset input 21 EPRTEST l EEPROM data setup mode input 22 STEST l Monitor operation mode input 23 STEST2 Touch panel test mode input 24 PNLXV O Hi output is carried out when X directions is detected 25 PNLYV O Hi output is carried out when Y directions is detected 26 NC I/O Not used 27 SDA IC data input / output 28 SCL O IC clock output 29 PIPRES O IC reset output 31 PNLVD Touch panel power supply control output 33 VSS1 GND 34-37 NC Not used 38 ROMDATA Not used 39 ROMCLK Not used 40 POMCS Not used 41,42 NC Not used 44 INVPUL Inverter pulse output 45 BEEP Not used 46 EPRCS O EEPROM chip select output 47 EPRSK O EEPROM serial clock output 48 EPRDO O EEPROM serial data output 49 EPRDI l EEPROM serial data input 50 EPRPROT O EEPROM memory protect output 51 TESTIN l Chip test input 55,56 NC Not used 57 LCDTYPE1 l LCD panel type detect input1 58 NC Not used 59 LCDTYPE2 l LCD panel type detect input2 60 RESET l Reset input 61 REMIN l Remote control data input 62 VDDSENS l Power supply sense input 64 ROT1 Rotary encoder input1 65 LCDLR Not used 66 TVIND Not used 67 VSS0 GND 68 VDD1 Power supply 69 X2 Crystal oscillator connection pin 70 X1 Crystal oscillator connection pin 71 VPP Not used 72 XT2 Not used -Pin Functions(PE5479A) l 30 LSWVDD O LCD micro computer power supply control output 43 INVBST O Not used 52 NC Not used 53 LDIMMER Not used 54 LBKL O LCD micro computer back light power supply control output 63 ROT0 I Rotary encoder input0 I O 32 NC Not used O www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 245 5 6 7 8 5 6 7 8 C D F A B E Pin No. Pin Name I/O l l l Function and Operation 73 XT2 GND 74 VDD0 Power supply 75 AVDD A/D converter power supply 76 KEY0 Analog key data input 0 77 KEY1 Analog key data input 1 78 KEY2 Analog key data input 2 79 I 80 TEMPSEN Temperature sense input (back light boost) * PE5479A 80 61 60 41 1 21 40 20 l KEY3 Analog key data input 3 1 2 3 4 5 6 7 8 9 10 20 19 18 17 16 15 14 13 12 11 CTIMR OVP ENA SST VDDA GNDA V2500 RT1 FB COMP NDRV_B PDRV_A CT RT PGND LCT DIM LPWM PDRV_C NDRV_D Protection NDR_B PDR_A ZVS Phase-Shift Controller HF OSC PDR_C NDR_D Burst- Mode Control OVP ENA hys. COMP hys. COMP 1.5V 2V + - + - Reference OPLAMP - + EA - + Ignition 1.25V 2V 2.50V sub. POFF POFF I=3uA I=6uA Soft Start ACTIVE "HIGH" OZ961ISN www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 246 1 2 3 4 1 2 3 4 C D F A B E S-29221BR0I-J8T1 NC VCC CS SK protect GND DO DI 1 2 3 4 8 7 6 5 Memory Aray Address Decoder Mode Decode Logic Data Resistor Output Buffer Clock Pulse Counter Voltage Ditector Clock Oscillater Write Protect Circuit GND OUT VCC 1 4 2 3 GND Current amp TPS850 1 12 36 25 13 24 48 37 BD6171KV - Pin Arrangement Chart www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 247 5 6 7 8 5 6 7 8 C D F A B E EN1 32 42 41 33 34 35 36 21 17 16 15 14 26 20 19 18 2 27 44 1 37 38 39 40 29 30 43 31 3 28 45 46 47 48 4 5 7 6 13 12 10 9 11 25 24 22 23 EN2 EN5 1V 3V VCC VREF VREF SS1 SOFT START SOFT START INVERT DELAY GATE CRAMP LATCH LATCH UVLO CP POS CP NEG TSD OSC FET DRIVER ERROR AMP FET DRIVER ERROR AMP PWM DVCC PVCC3 0.6 VREGA EN3 EN4 OUT3 OUT1 RESET RESET VREGA VREGA 0.6V 0.6V OUT2 OUT4 FB4 PGND4 VO4DET VREGA VO5DET GND DGND SGND 0.6V 0.6V PGND5 FB5 DVCC 5VREG OUT5 PVCC5 SYNC RT FB2 INV2 SS2 VO1DET OCPC1 2V 2V FB1 INV1 1V VO2DET OCPC2 1V VREGA VREGA VREF OUT OUT CL2 VS2 PVCC4 EN4 EN5 CL1 VS1 PVCC2 FB3 VO3DET PVCC1 VREGB EN1 PWM OSCILLATOR EN2 EN3 + + - + - - + - + + + - + - - + - + - + - + - + - + + - + - + - - + - + BD6171KV - Block Diagram Chart www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 248 1 2 3 4 1 2 3 4 C D F A B E - Pin Functions (PE5478A) Pin No. Pin Name I/O Function and Operation 1 STOC O Navigation microcomputer data output (UART) 2 FCONT O AM noise measures output 3 csensout O Flap close sense output 4,5 NC Not used 6 MTOS I Monitor microcomputer data input (UART) 7 STOM O Monitor microcomputer data output (UART) 8 TSCK Not used 9 EVDD Power supply 10 EVSS GND 11 SWACPW O Monitor microcomputer power supply output 12 SYSPW O System power supply output 13 brst O P-BUS : Reset output 14 bsrq I P-BUS : Communication request input 15 BSI I P-BUS : Data input 16 BSO O P-BUS : Data output 17 BSCK I/O P-BUS : Clock input/output 18,19 VSELIN1,2 I AV-BUS : VSEL input 1,2 20 avonin I AV-BUS : AVON input 21 VPP VSS 22 VCK O E. VOL : Clock output 23 VDT O E. VOL : Data output 24 VST O E. VOL : Strobe pulse output 25 MUTEVOL O E. VOL : Mute output 26 RX I IP-BUS : Data input 27 TX O IP-BUS : Data output 28 IPPW O IP-BUS : Driver power supply control output 29 ASENBO O IP-BUS : ACC sense output 30 BRXEN O P-BUS : Possible to receive output 31 ROMDATA Not used 32 ROMCLK Not used 33 ROMCS Not used 34 reset I System reset input 35 XT1 Not used 36 XT2 Not used 37 REGC Not used 38 X2 Crystal oscillator connection pin 39 X1 Crystal oscillator connection pin 40 VSS GND 41 VDD Power supply 42 PCL Not used 43,44 PULSE0,1 I Pulse detect input 0,1 45,46 MOT0,1 O Flap motor driver output 0,1 47 MOTPW O Flap motor power supply output 48 opensw I Flap angle OPEN position sense input 49 homesw I Flap angle CLOSE position sense input 50 ejectsw I Flap angle CD EJECT position sense input 51 MUTENS O Mute output at the time of MIX 52 nosell O Navigation voice Lch MIX control output 53 noselr O Navigation voice Rch MIX control output 54 DRAMPW O Navigation control DRAMPW output 55 CCON O Navigation control CCON output 56 IRQPW O Navigation control IRQPW output 57 SYSRST O Navigation control RSTOUT output 58 BVDD Power supply 59 BVSS GND 60 ANTPW O Auto antenna control output 61 ILMPW O Illumination power supply switch output 62 FLAPILM O Panel illumination switch output 63 MEMOLED O MEMO button LED control output 64 dalmon O Consumption current reduction output www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 249 5 6 7 8 5 6 7 8 C D F A B E Pin No. Pin Name I/O Function and Operation 65 AMPSTBY O Amp stand-by output 66 fanup O Fan motor control output 67 MUTEALL O Mute output 68 MUTEAMP O Amp mute output 69,70 VFSEL0,1 O Front monitor source select output 0,1 71 fvmute O Front monitor mute output 72 VRSEL O Rear monitor source select output 73 REARON O Rear monitor ON output 74 AVDD A/D converter power supply 75 AVSS A/D converter GND 76 AVREF A/D converter reference voltage 77 TUNSL I Tuner signal level input 78 NTEMPIN I Navigation temperature sense input 79 WREMIN I Wired remote control analog value input 80 wcont I Wired remote control SEL input 81 rst# I Navigation control reset input 82 xccstby I Navigation stand-by OK input 83 CPUWDT I Navigation watch dog timer input 84 TELIN I Telephone mute input 85 PBSENS I Parking brake sense input 86 revsens I Reverse gear sense input 87 TESTIN I Test mode input 88 TIMEOUT I Timeout input 89 NMI Pull down 90 bsens I Backup sense input 91 asens I ACC sense input 92 ilmsens I Illumination sense input 93 dvdeject I DVD EJECT key input 94 cdeject I CD EJECT key input 95 TUNCE1 O Tuner : PLL chip enable output 96 tunce@ O Tuner : EEPROM chip enable output 97 TUNPDI I Tuner : Data input (SIO) 98 TUNPDO O Tuner : Data output (SIO) 99 TUNCK O Tuner : Data clock output (SIO) 100 CTOS I Navigation microcomputer data input (UART) * PE5478A 30 31 50 51 100 1 81 80 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 250 1 2 3 4 1 2 3 4 C D F A B E 6 4 1 2 5 9 11 14 12 13 8 10 VCC 4B 4A 3B 3A 3Y 1A 1B 1Y 2A 2B 2Y GND 4Y 7 3 * TC74VHCT08AFTS1 CLAMP 6 5 4 1 2 3 6dB AMP 75Ω DRIVER V+ GND Vin Power Save Vout Vsag LPF NJM2561F1 16 15 14 13 12 11 10 9 NC NC IN2A NC 1 2 3 4 5 6 7 8 OUT1 NC GND NC VCC + + OUT2 VREF NC NC IN2B IN1A IN1B TA2050FS1 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 251 5 6 7 8 5 6 7 8 C D F A B E - Pin Functions(BA5835FP) Pin No. Pin Name Function and Operation 1 VR Input pin for reference voltage 2 OPIN2(+) Input pin for non-inverting input for CH2 preamplifier 3 OPIN2(-) Input pin for inverting input for CH2 preamplifier 4 OPOUT2 Output pin for CH2 preamplifier 5 OPIN1(+) Input pin for non-inverting input for CH1 preamplifier 6 OPIN1(-) Input pin for inverting input from CH1 preamplifier 7 OPOUT1 Output pin for CH1 preamplifier 8 GND Ground pin 9 MUTE Mute control pin 10 POWVCC1 Power supply pin for CH1, CH2, and CH3 at "Power" stage 11 VO1(-) Driver CH1 - Negative output 12 VO1(+) Driver CH2 - Positive output 13 VO2(-) Driver CH2 - Negative output 14 VO2(+) Driver CH2 - Positive output 15 VO3(+) Driver CH2 - Positive output 16 VO3(-) Driver CH2 - Negative output 17 VO4(+) Driver CH4 - Positive output 18 VO4(-) Driver CH4 - Negative output 19 POWVCC2 Power supply pin for CH4 at "Power" stage 20 GND Ground pin 21 CNT Control pin 22 LDIN Loading input 23 OPOUTSL Output pin for preamplifier for thread 24 OPINLSL Input pin for preamplifier for thread 25 OPOUT3 CH3 preamplifier output pin 26 OPIN3(-) Input pin for inverting input for CH3 preamplifier 27 OPIN3(+) Input pin for non-inverting input for CH3 preamplifier 28 PREVCC PreVcc BA5835FP 1 14 15 28 IN 1 GND 2 OUT 3 Bandgap Reference Thermal Protection +- NJM2885DL1-33 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 252 1 2 3 4 1 2 3 4 C D F A B E - Pin Functions(PE5454B) Pin No. Pin Name I/O Format Function and Operation 1 AVREF A power supply Positive power supply(5V) 2 AVSS A power supply GND 3 RFOK O C Output of state of RFOK 4 NC Not used 5 EVDD E power supply Positive power supply 6, 7 NC Not used 8 IC/FLMD0 IC : VSS direct connection/FLMOD0 : Pull-down 9 VDD Positive power supply(5V) 10 REGC Connected to the capacity stabilizing output of the regulator 11 VSS GND 12 X1 I Oscillator connection for mainclock 13 X2 Oscillator connection for mainclock 14 reset I System reset input 15 XT1 I Connected to the oscillator for subclock (connected to VSS via the resistor) 16 XT2 Connected to the oscillator for subclock(Open) 17 NC Connected to EVDD or EVSS via the resistor 18 NC Not used 19 xint I C CD LSI interruption signal input 20 NC Connected to VSS via the resistor 21 brst I P-Bus reset input 22 BSI I P-Bus serial data input 23 BSO O C P-Bus serial data output 24 bsck I/O /C P-Bus serial clock input/output 25 FTXD O C For flash rewriting output(transmitted signal) 26 FRXD I For flash rewriting input(received signal) 27 BRXEN I/O /C It is possible to receive P-Bus input/output 28 bsrq I/O /C P-Bus service request demand input/output 29 NC Not used 30 DSCSNS I Disc state sense input 31 8EJ(S905) I Input of detection of 8 cm disc ejection 32 12EJ(S904) I Input of detection of 12 cm disc ejection 33 EVSS E power supply GND 34 EVDD E power supply Positive power supply 35, 36 SRAMLEVEL0, 1 O C SRAM level meter output 37 EMPH O C Emphasis information output 38 emph O C Emphasis information output 39-42 NC Not used 43 adena O C A/D reference voltage supply control output 44 LRCKOK O C (DOUT mute output) 45 SRAMLEVEL2 O C SRAM level meter output 46 CD3VON O C CD +3.3V power supply control output 47 CONT O C Servo driver power supply control output 48 xrst O C CD LSI reset control output 49 VDCONT O C VD power supply control output 50 ROMDATA I/O /C E2PROM data input/output 51 ROMCS O C E2PROM chip selection output 52 ROMCK O C E2PROM clock output 53 LOEJ O C The direction change output of LOAD/EJECT 54 CLCONT O C Driver input change output 55 CDMUTE O C CD mute control output 56-58 NC Not used 59 xcs O C CD LSI chip selection output 60 NC Not used 61 xwait I CD LSI write control signal input 62 CLKOUT O C Internal system clock output(Open) 63 LOCK I Spindle lock input 64 NC Not used 65 xwrite O CD LSI write control signal output 66 NC Not used www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 253 5 6 7 8 5 6 7 8 C D F A B E Pin No. Pin Name I/O Format Function and Operation 67 xread O CD LSI read control signal output 68 XASTB O CD LSI address strobe output 69 BVSS B power supply GND 70 BVDD B power supply Positive power supply 71-83 AD0-12 I/O /C Address/data Bus 0-12 84-86 NC Not used 87 FMODE I For flash rewriting Connected to VSS via the resistor 88 FLRQ O C For flash rewriting 89-93 NC Not used 94 csens I Flap closing sense input 95 TYPE_A/D I CD-DA analog/digital output change setup 96 testin I Chip check test program starting input 97 HOME I Home SW sense input 98 TEMP I Temperature information sense input 99 VDSENS I VD power supply short sense input 100 NC Not used * PE5454B 25 26 50 51 75 76 100 1 Format Meaning C CMOS www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 254 1 2 3 4 1 2 3 4 C D F A B E - Pin Functions(UPD63763GJ) Pin No. Pin Name I/O Function and Operation 1 D.VDD Power supply for digital circuits 2 D1.GND GND for 1.6V digital circuits 3 reset I Input of reset 4-8 AB12-8 I Address bus 12-8 from the microcomputer 9-16 AD7-0 I/O Address/data bus 7-0 to the microcomputer 17 cs I Chip selection 18 ASTB I Address strobe 19 read I Control signals(read) 20 write I Control signals(write) 21 wait O Control signals(wait) 22 INTQ O Interruption signals to the external microcomputer 23, 24 IFMODE0, 1 I Switching the microcomputer I/F 0, 1 25 D1.VDD Power supply for 1.6V digital circuits 26 DA.VDD Power supply for DAC 27 ROUT O Output of audio for the right channel 28 DA.GND GND for DAC 29 REGC Connected to the capacitor for band gap 30 DA.GND GND for DAC 31 LOUT O Output of audio for the left channel 32 DA.VDD Power supply for DAC 33 X.VDD Power supply for the crystal oscillator 34 XTAL I Connected to the crystal oscillator(16.9344MHz) 35 xtal O Connected to the crystal oscillator(16.9344MHz) 36 X.GND Ground for the crystal oscillator 37 VDDREG15 Control of 1.6V regulator 38 PWMSW0 I Setup 0 for PWM output(SD, MD) 39-41 TEST3-1 I Connected to GND 42 PWMSW1 I Setup 1 for PWM output(FD, TD) 43 TESTEN I Connected to GND 44 D1.GND GND for 1.6V digital circuits 45 DIN I Input of audio data 46 DOUT O Output of audio data 47 SCKIN I Clock input for audio data 48 SCKO O Clock output for audio data 49 LRCKIN I Input of LRCK for audio data 50 LRCK O Output LRCK for audio data 51 xtalen I Permission to oscillate 16.9344MHz 52 D1.VDD Power supply for 1.6V digital circuits 53 RFCK/HOLD O Output of RFCK/HOLD signal 54 WFCK/MIRR O Output of WFCK/MIRR signal 55 PLCK/RFOK O Output of PLCK/Output of RFOK 56 LOCK/RFOK O Output of LRCK/Output of RFOK 57 C1D1/C8M O Information on error correction/C8M : 8MHz 58 C1D2/C16M O Information on error correction/C16M : 16MHz 59 C2D1/RMUTE O Information on error correction/Mute for Rch 60 C2D2/LMUTE O Information on error correction/Mute for Lch 61 C2D3/SHOCK O Information on error correction/Detection of vibration 62 D1.GND GND for 1.6V digital circuits 63 C33M O Output of 33.8688MHz(CLK for SDRAM) 64 (rcs) O DRAM cs 65 RA11 O Output of DRAM address 11 66 (CKE) O Output of DRAM CKE 67 ras O Output of DRAM ras 68 cas)(LDQM) O Output of DRAM lower cas(LDQM) 69 cas!(UDQM) O Output of DRAM upper cas(UDQM) 70 we O Output of DRAM we 71 oe(cas) O Output of DRAM oe(cas) 72 D.GND Ground for digital circuits 73-88 RDB0-15 I/O Input/output of DRAM data0-15 89-99 RA0-10 O Output of DRAM address0-10 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 255 5 6 7 8 5 6 7 8 C D F A B E Pin No. Pin Name I/O Function and Operation 100 D.VDD Power supply for digital circuits 101 FD+ O Output of focus drive PWM + 102 FD- O Output of focus drive PWM - 103 TD+ O Output of tracking drive PWM + 104 TD- O Output of tracking drive PWM - 105 SD+ O Output of thread drive PWM + 106 SD- O Output of thread drive PWM - 107 MD+ O Output of spindle drive PWM + 108 MD- O Output of spindle drive PWM - 109 REFOUTSV O REFOUT for servo 110 AD.VDD Power supply for ADC 111 EFM O Output of EFM signals 112 ASY I Input of asymmetry 113 ATEST O Analog tests 114 RFI I Input of RF 115 AD.GND Ground for the analog system 116 AGCO O Output of RF 117 C3T O Connection to the capacitor for detecting 3T 118 AGCI I Input of AGC 119 RFO O Output of RF(AGC) 120, 121 EQ2, 1 I Equalizer 2, 1 122 RF2- I Reversal input of RF2 123 RF- I Reversal input of RF 124 A.GND Ground for the analog system 125 A I Input of A 126 C I Input of C 127 B I Input of B 128 D I Input of D 129 F I Input of F 130 E I Input of E 131 VREFIN I Input of reference voltage 132 A.VDD Power supply for the analog system 133 REFOUT O Output of reference voltage 134 REFC I Connected to the capacitor for output of REFOUT 135 FE- I Reversal input of FE 136 FEO O Output of FE 137 ADIN I Input of FE, TE A/D converter 138 TE- I Reversal input of TE 139 TEO O Output of TE 140 TE2 O TE2 141 TEC I TEC 142 LD O Output of LD 143 PD I Input of PD 144 D.GND Ground for digital circuits * UPD63763GJ 72 73 108 109 36 37 1 144 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 256 1 2 3 4 1 2 3 4 C D F A B E INTP0-INTP6 NMI INTC TI00,TI01, TI10,TI11 TO0,TI1 TI2/TO2 TI3/TO3 TI4/TO4 TI5/TO5 SO0 SO1/TXD0 SIO SI0 SCK0 ASCK1 SI1/RXD0 SCK1/ASCK0 TXD1 RXD1 SCK2 SO2 SI2 CSI0/IIC CSI1/UART0 UART1 CSI2 DMAC : 3ch Port Timer for clock Watch dog timer RAM ROM PC System Registor General Register (32bit x 32) Multplier (16 x 16->32) 32bit Ballel Siffer CPU BCU ALU P110-P113 P100-P107 P90-P96 P60-P65 P50-P57 P40-P47 P30-P37 P20-P27 P10-P15 P00-P07 P80-P83 P70-P77 ANI0-ANI11 RTP0-RTP7 P114 RTPTRG ADTRG AVss AVdd AVref P120 Instruction Queue CG A/D Converter RTP HLDRQ(P96) HLDAK(P95) ASTB DSTB/RD(P93) R/W/WRH(P92) UBEN(P91) LBEN/WRL(P90) WAIT AD0-AD15 (P40-P47,P50-P57) A16-A21(P60-P65) A13-A15(P34-P36) A1-A2(P100-P107,P110-P113) X1 XT1(P114) XT2 X2 BVss IC Vss Vdd BVdd CLKOUT RESET Timer/ Counter * PE5430A - Pin Arrangement Chart - Block Diagram Chart www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 257 5 6 7 8 5 6 7 8 C D F A B E No. Symbol I/O Explain 1 AMANT I AM antenna input AM antenna input high impedance AMANT pin is connected with an all antenna by way of 4.7µH. (LAU type inductor) A series circuit including an inductor and a resistor is connected with RF ground for the countermeasure against the hum of power transmission line. 2 RFGND RF ground Ground of antenna block 3 FMANT I FM antenna input Input of FM antenna 75Ω Surge absorber(DSP-201M-S00B) is necessary. 4 VCC power supply The power supply for analog block. D.C 8.4V ± 0.3V 5 SL O signal level Output of FM/AM signals level 6 CE2 I chip enable-2 Chip enable for EEPROM ”Low” active 7 WC I write control You can write EEPROM, when EEPROM write control is “Low”. Ordinary non connection 8 CE1 I chip enable-1 Chip enable for AF•RF ”High” active 9 CK I clock Clock 10 DI I data in Data input 11 NC non connection Not used 12 OSCGND osc ground Ground of oscillator block 13 ROM_VDD power supply Power supply for EEPROM pin 13 is connected with a power supply of micro computer. 14 DO O data out Data output 15 DGND digital ground Ground of digital block 16 NC non connection Not used 17 VDD_3.3 power supply The power supply for digital block. 3.3V ± 0.2V 18 NC non connection Not used 19 NC non connection Not used 20 NC non connection Not used 21 NC non connection Not used 22 AUDIOGND audio ground Ground of audio block 23 L ch O L channel output FM stereo “L-ch” signal output or AM audio output 24 R ch O R channel output FM stereo “R-ch” signal output or AM audio output FMRF ANT adj RF adj FM ANT T51 CF52 CF51 RFGND OSCGND DGND AUDIOGND NC VCC VDD_3.3 3.3V 2.5V IC 4 3.3V 2.5V ← IC 2 2.5V WC CE2 ROM_VDD SL DI CK CE1 NC DO NC NC NC NC 7 6 13 5 10 9 8 11 14 18 19 20 21 1 3 2 12 15 22 16 4 17 IC 1 3.3V AM ANT FMRF ATT LPF OSC IC 3 EEPROM 5.0V IC 5 5V 3.3V ← ATT MIXER, IF AMP DET, FM MPX 24 23 Rch Lch - FM/AM Tuner Unit www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 258 1 2 3 4 1 2 3 4 C D F A B E 7.3 EXPLANATION 7.3.1 MECHANISM DESCRIPTIONS - FLAP Operation Specification 1. Outline Slide open method is adopted, and 4 positions of closed, angle adjustment, half open and full open are considered the basic positions. (1) Closed This status is always taken once at power supply ON since flap is completely closed and it is the reference point for flap operation startup. (2) Angle Adjustment Position for visibility adjustment. The angle can be adjusted in 5 stages from the closed position to the maximum angle (approximately 20°) within the adjustable range by the angle key. The angle has toggle operation, and it executes close operation as follows when it reaches the maximum angle. (3) Half Open Position for DISC replacement on upper stage (CD). It slides down to angle 12 when OPEN/CLOSE key is pressed quickly at the closed or angle adjustment position. CD insertion/EJECT operation is possible from this position. At the half open position, LAST position is restored when OPEN/CLOSE key is pressed quickly. Approx. 62.5° CD 0° ~ 21° www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 259 5 6 7 8 5 6 7 8 C D F A B E (4) Full Open Position for DISC replacement on lower stage (DVD). This position is set when OPEN/CLOSE key is pressed for more than 2 second at all positions except full open. Map DISC (DVD) can only be inserted/ejected at this position. At the full open position, the closed position is restored when OPEN/CLOSE key is pressed for more than 2 second, and LAST position is restored when it is pressed quickly. (5) Error Angle Besides the above 4 positions that can be operated by the user, this system has the error angle (approx. 45°) as an escape from danger in case of stopping due to an obstruction. If operation becomes impossible in the angle of 45° or smaller, it opens to this position so that the obstruction (assuming a finger getting caught) can be released completely. CD DVD (Map DISC) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 260 1 2 3 4 1 2 3 4 C D F A B E 2. FLAP Operation Specification (1) Reset Start • No operation at full open position. It moves to the closed position at positions other than full open. (2) ACC ON • No operation at full open or closed position. • At ANGLE/half open position, it closes once and then returns to the LAST position. (3) ACC OFF • No operation at closed position. • It closes in 3 seconds when it is at positions other than closed. However, it shifts to standby status when DISC is at half position. • If it is in FLAP operation, it closes after completing the current operation. (4) ACC OFF/ON • If ACC ON is detected within 3 seconds after ACC OFF, the current condition is continued. • DISC is at half position, it is closed after loading. * “ACC detection” here includes chatter period. That is, “ACC detection within 3 seconds” means 2.5 seconds + chatter period 0.5 seconds, and the actual ACC OFF/ON interval is “within 2.5 seconds.” (5) DISC Insertion • When DISC is inserted for either CD or DVD, it restores to the LAST position. (6) ANGLE Key • Angle is adjusted in 5 steps from FULL CLOSE (0°) to the maximum angle (approx. 20°) (1STEP slides in horizontal direction by approx. 6mm). • It is closed when the system is at the maximum angle. • Though continuous operation is executed by pressing the key for more than 1 second, it stops when the maximum angle is reached. • If the opening exceeds the maximum angle, ANGLE key operation becomes disabled. (7) Pressing OPEN key quickly • If the system is at FULL CLOSE/ANGLE position, it opens to the half open position (CD insertion opening position) in 1 action. • If it is at half open position, it restores the LAST position. • If it is at half open position and DISC at half position, it restores the LAST position after reloading. • CD EJECT key becomes enabled at the opening of half open position or later by this operation. (8) OPEN Key Pressed for 2 Second or Longer • If FLAP angle is at positions other than full open, it moves to full open position. • DVD EJECT key becomes enabled only at the full open position by this operation. (9) Obstructions a. During CLOSE operation • It opens to 45° if the angle at which operation was disabled was less than 45°. • It shifts to the open direction by 1 angle if the angle at which operation was disabled was 45° or larger. b. During OPEN operation • It shifts to the close direction by 1 angle from the angle at which operation was disabled. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 261 5 6 7 8 5 6 7 8 C D F A B E 0 0 1 1 0 0 1 1 0 0 1 1 0 0 1 1 0 0 1 1 0 0 1 1 0 0 1 1 0 0 1 1 0 0 1 1 0 0 1 1 0 0 1 1 0 0 1 1 0 0 1 1 0 0 1 1 0 0 1 1 0 0 1 1 0 0 1 1 0 0 1 1 0 0 1 1 0 0 1 1 0 0 1 1 0 0 1 1 0 0 1 1 0 0 1 1 0 0 1 1 0 0 1 1 0 0 1 1 0 0 1 1 0 0 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 0 0 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 0 0 0 0 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 ANGLE 0 (FULL CLOSE) ANGLE 1 ANGLE 2 ANGLE 3 ANGLE 4 ANGLE 5 – – – – – – HALF OPEN (CD insertion) – FULL OPEN (DVD insertion) CD EJECT OKSENS OPEN SENS CLOSE SENS POSITION 0 – 1 0 – 1 0 – 1 C L O S E O P E N Pulse A Pulse B 3. Correlation of slide position and angle www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 262 1 2 3 4 1 2 3 4 C D F A B E 4. Emergency Process 4.1. There are following 7 FLAP-related emergency conditions: (1) Reversed insertion of a CD (2) Insertion of an unreadable CD (3) Half loading of CD (4) Reversed insertion of a DVD (5) Insertion of an unreadable DVD (6) Half loading of DVD (7) When there is a physical obstruction on sliding track 4.2. FLAP process in emergency conditions For (1), (2), (4), and (5), • The same process as normal insertion (LAST position after loading) is executed and then the error message is displayed. • No automatic ejection. For (3) and (6), • The same process as normal insertion (LAST position after loading) is executed. • Basically, no sliding operation is executed if emergency status is detected before the sliding operation. • If emergency occurs while sliding in open direction, it slides in close direction by 1 position and then stops sliding. • If emergency occurs while sliding in close direction, it slides in open direction by 1 position and then stops sliding. For (7), • If emergency occurs while sliding in open direction, it slides in close direction by 1 position and then stops sliding. • If emergency occurs while sliding in close direction, it slides in open direction by 1 position and then stops sliding. • If sliding waveform change by angle key pressing, etc. does not appear for 500ms due to obstruction, etc., it slides in the opposite direction by 1 position and stops sliding. If it does not return to the position to be returned by 1 position in error even after 750ms, it stops at the position. • If close sense SW does not turn ON for 500ms due to obstruction, etc. during transition to full close, it slides in the open direction from the current position by 1 position and then stops operating. • If open sense SW does not turn ON for 500ms due to obstruction, etc. during transition to half or full open, it slides in the close direction from the current position by 1 position and then stops operating. 4.3. Emergency specification in CD/DVD disc error (above (1) – (6)) • Operation is basically identical to normal discs, and the only special process is error message display. • No processes such as automatic ejection of CD/DVD in error are executed basically. • When a disc is inserted once, it can only be ejected by the DISC eject key. 4.4. Emergency display and alarm tone • In case of a CD/DVD error (including reversed disc), the corresponding error message is displayed so that each error condition can be recognized. • An alarm tone is sound to notify sliding disabled conditions when sliding operation becomes disabled. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 263 5 6 7 8 5 6 7 8 C D F A B E 5. FUNCTION CHART ANGLE key 1 step DOWN ANGLE 1 Quick pressing of OPEN/CLOSE Half open Pressing of OPEN/CLOSE for more than 1 second Full open ACC ON No change ACC OFF No change Normal (1) Full Close (ANGLE 0) ANGLE key Angle +1 Full close when ANGLE is 7 Quick pressing of OPEN/CLOSE Half open Pressing of OPEN/CLOSE for more than 1 second Full open ACC ON Return to LAST position after full close ACC OFF Full close Normal (2) Angle Adjustment (ANGLE 1~5) ANGLE key Disabled Disabled Quick pressing of OPEN/CLOSE Return to LAST position Return to LAST position after reloading Pressing of OPEN/CLOSE for more than 1 second Full open Full open ACC ON Return to LAST position after full close Return to LAST position after reloading ACC OFF Full close No change Normal CD half (3) Half Open CD insertion Return to LAST position CD EJECT key CD ejection Disabled ANGLE key Disabled Disabled Disabled Quick pressing of OPEN/CLOSE Return to LAST position Return to LAST position after reloading Return to LAST position after reloading Pressing of OPEN/CLOSE for more than 1 second Disabled Disabled Disabled ACC ON No change Return to LAST position after reloading Reloading only ACC OFF Full close No change No change Normal CD half DVD half (4) Full Open CD insertion Return to LAST position DVD insertion Return to LAST position CD EJECT key CD ejection Disabled DVD EJECT key DVD ejection Disabled During CLOSE operation OPEN to 45° 1 angle OPEN During OPEN operation 1 angle CLOSE 1 angle CLOSE (5) Obstruction Less than 45° 45° or larger www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 264 1 2 3 4 1 2 3 4 C D F A B E 7.3.2 OPERATIONAL FLOW CHART STAGE bsens in asens in AMPSTBY out MUTEALL out MUTEVOL out SWACPW out ASENBO out IPPW out dalmon out CCON out DRAMPW out SYSRST out IRQPW out CPUWDT in rst# in xccstby in ACC ON STAND-BY TASK MAIN LOOP ON chattering : 500ms 200ms 350ms 24ms 64ms 100ms 1ms Waiting to 100ms after SYSRST ON. Waiting to 1ms after rst# ON. If SOURCE ON, M www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 265 5 6 7 8 5 6 7 8 C D F A B E ACC OFF IDLE STOP STAND-BY TASK OOP OFF chattering : 8ms to 10ms 5ms 3 seconds Dropped down after waiting for 500µs. (Guarantee time as the SDRAM back up.) OURCE ON, MUTEVOL release. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 266 1 2 3 4 1 2 3 4 C D F A B E 8. OPERATIONS Navigation Unit This section gives information about the names of the parts and main features using the buttons. (1) MAP button Press to view the map or return to guidance. Also, when the map is scrolling, pressing this button returns you to the display of the map of your surroundings. Use to switch the view mode of the navigation when the map of your surround- ings is displayed. If you press this button while in the audio operation screen, the screen changes to the Navigation map screen. (2) AV button Use to switch between Navigation map screen and audio operation screen. (3) VOL (+/–) button Pressing on the + side of the button to increase the volume while pressing on the - side of it to decrease the volume. 1 2 3 4 5 6 7 8 9 0 ! @ # $ % ^ & * ( ) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 267 5 6 7 8 5 6 7 8 C D F A B E (4) SRC (SOURCE) button This unit is turned on by selecting a source. Press to cycle through all of the available sources. Press and hold to turn the source off. (5) RESET button Press to return to the factory settings (initial set- tings). Some information items are not erased. (6) Joystick Move to do manual seek tuning, fast forward, reverse and track search controls, etc. Push to display the menu for the Audio operation. (7) OPEN/CLOSE button Press to open or close the LCD panel and access the CD and DVD-ROM loading slot. Operation varies depending on the position of the LCD panel and the length of time of pressing this but- ton. (8) ANGLE button Press to change the LCD panel angle. (9) DEST button Press to display the Destination menu. (10) INFO button Press to display the Info/Traffic menu. (11) TRFC button When the XM tuner (GEX-P10XMT) is con- nected*: Preset button for XM Instant Traffic & Weather audio service. Select XM audio source, and find appropriate Instant Traffic & Weather channel. Hold down this button while on this channel to assign preset. When the XM tuner (GEX-P10XMT) is not connected: Not used. (12) P.ADJ/B.LIGHT button Press to enter the PICTURE ADJUST mode. Press and hold to turn off the back light of the LCD panel. To turn on the back light, press this button again. (13) MEMO button When the XM tuner (GEX-P10XMT) is con- nected and the XM source is selected*: Press and hold this button to memorize the track currently being played. This button flashes when the memorized track is playing on a station other than the one which you are currently on. If you press this button while it is flashing, the station changes to the one play- ing your track. When the XM tuner (GEX-P10XMT) is not connected: Not used. (14) Ambient light sensor Senses ambient light. This system automatically adjusts the brightness of the display to compen- sate for ambient light. (15) LCD panel (16) LCD screen (17) CD loading slot Insert a CD to play. (18) DVD-ROM loading slot Insert a DVD Map Disc. (19) CD EJECT button Press to eject the disc from the CD loading slot. (20) DVD-ROM EJECT button Press to eject the disc from the DVD-ROM load- ing slot. *: GEX-P10XMT sold separately is required, in addition to an active subscription to XM Satel- lite Radio service. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 268 1 2 3 4 1 2 3 4 C D F A B E Turning the Unit On and Select- ing a Source • If the program is not installed, see Opera- If th i t i t ll d O tion Manual and install the program. 1 Turn the ignition switch (ACC) ON. The Navigation System’s power supply comes on. 2 Press SRC button to select a source. Press SRC button repeatedly to switch between the following sources: “XM” (XM tuner) — “ SIRIUS ” (SIRIUS tuner) —“RADIO ” (tuner) — “TV” (television) — “AV” (video input) — “S-DVD” (DVD player/ multi-DVD player) — “CD” [CD, MP3/WMA/ WAV](built-in CD drive) — “M-CD” (multi-CD player) — “EXT-1” (external unit 1) — “EXT- 2” (external unit 2) — “AUX” (Auxiliary equip- ment) Press and hold to turn the source off. In the following cases, the sound source can- not be used — When a unit corresponding to each source is not connected to this unit. — When no disc is set in the CD loading slot. — When no disc is set in the DVD-player (“S- DVD ”). — When no magazine is set in the multi-CD player. — When no magazine is set in the multi-DVD player. — When the “AUX” (auxiliary input) is set to off. — When the “AV INPUT ” (video input) is not set to “VIDEO”. External unit refers to a Pioneer product (such as one available in the future) that, although incompatible as a source, enables control of basic functions by this unit. Two external units can be controlled by this unit. When two exter- nal units are connected, the allocation of them to external unit 1 or external unit 2 is automatically set by this unit. When this unit’s blue lead is connected to the vehicle’s auto-antenna relay control terminal with the “ AUTO ANTENNA” is set to “SOURCE”, the vehicle’s antenna extends while this unit’s source is turned on. To retract the antenna, turn the source off. Adjusting the Volume • Use VOL (+/–) to adjust the audio sound level. With this product, press VOL (+/–) to increase or decrease the volume. To adjust the navigation volume, go to the navigation menu. Turning the Source Off • Press SRC button and hold until the source turns off. This product can be switched off by turn- ing the ACC (ignition) OFF. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 269 5 6 7 8 5 6 7 8 C D F A B E Inserting/Ejecting a Disc • Do not use with the LCD panel left open. If D t ith th LCD l l ft If LCD panel is left open, it may result in injury in the event of an accident. • Do not open and close the LCD panel with D t d l th LCD l ith hands by force. This may cause malfunc- tion. • When opening, closing and adjusting the angle of the LCD panel, be careful not to get your finger caught. The LCD panel will be closed automatically with the turning of the ignition switch. Inserting a CD 1 Press OPEN/CLOSE button. The LCD panel opens halfway, and the CD loading slot appears. To close the LCD panel, press OPEN/ CLOSE button again. 2 Insert a CD into the CD loading slot. If you insert a CD, the LCD panel closes auto- matically, and then format reading will start. Make sure the CD loading slot is empty before inserting a CD into the slot. When a disc is already loaded in the CD loading slot, select the CD source by pressing SRC button. You can use AV button to switch between navigation map displays and audio operation displays. The built-in CD drive plays one, standard, 12- cm or 8-cm (single) disc at a time. Do not use an adapter when playing 8-cm discs. Do not insert anything other than a disc into the CD loading slot. If you cannot insert a disc completely or if a inserted disc is not recognized, check that the label side of the disc is up. Press CD EJECT button to eject the disc, and check the disc for damage before inserting the disc again. If the built-in CD drive does not operate prop- erly, an error message such as ERROR-11 may be displayed. Ejecting a CD 1 Press OPEN/CLOSE button. The LCD panel opens halfway. 2 Press CD EJECT button. The CD is ejected. 3 Press OPEN/CLOSE button. The LCD panel closes. CD EJECT button CD loading slot www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 270 1 2 3 4 1 2 3 4 C D F A B E Inserting the DVD Map Disc 1 Press and hold OPEN/CLOSE button. The LCD panel fully opens, and the DVD-ROM loading slot appears. To close the LCD panel, press OPEN/ CLOSE button again. 2 Insert the DVD Map Disc into the DVD- ROM loading slot. If you insert the DVD Map Disc, the LCD panel closes automatically, and then format reading will start. Make sure the DVD-ROM loading slot is empty before inserting a DVD Map Disc. Inserting the DVD Map Disc reboot DVD navigation mode. Do not insert anything other than a disc into the DVD-ROM loading slot. If you cannot insert a disc completely or if a inserted disc is not recognized, check that the label side of the disc is up. Press DVD-ROM EJECT button to eject the disc, and check the disc for damage before inserting the disc again. Ejecting the DVD Map Disc 1 Press and hold OPEN/CLOSE button. The LCD panel fully opens. 2 Press DVD-ROM EJECT button. The DVD Map Disc is ejected. 3 Press OPEN/CLOSE button. The LCD panel closes. Adjusting the LCD Panel Angle • Do not open and close the LCD panel with D t d l th LCD l ith hands by force. This may cause malfunc- tion. • When opening, closing and adjusting the angle of the LCD panel, be careful not to get your finger caught. The LCD panel will be closed automatically with the turning of the ignition switch. • Press ANGLE button to adjust the LCD panel to an easily viewable angle. You can adjust the angle of the LCD panel every time you press theANGLE button. long as you press ANGLE button and hold. When you press the ANGLE button with the maximum angle, the LCD panel closes all the way. The adjusted angle of the LCD panel will be memorized and the LCD panel will auto- matically return to this angle the next time the turning of the ignition switch (ACC) on. DVD-ROM EJECT button DVD-ROM loading slot www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 271 5 6 7 8 5 6 7 8 C D F A B E Multi-CD player Blue AV-BUS cable (supplied with TV tuner) IP-BUS cable IP-BUS cable (supplied with TV tuner) (sold separately) Black Blue *1 Blue Hide-away TV tuner (e.g. GEX-P6400TV) (sold separately) Hide-away XM tuner (GEX-P10XMT) (sold separately) Black Light gray 5 m (16 ft. 5 in.) GPS antenna Blue IP-BUS cable (supplied with XM tuner) Black *2 Black Black XM DATA cable (supplied with XM tuner) • When combining this product with GEX-P10XMT (sold separately), this connection must be required. • When installing the XM tuner in the trunk, etc., the optional cable (e.g. CD-600DC) (sold separately) is required. Black Antenna jack WIRED REMOTE Please see the Instruction Manual for the Wired Remote Control (sold separately). Power cord RCA connector This product Note: The XM tuner will not receive XM Radio ’s coverage area. When the XM tuner is not used, connect the IP-BUS cable*1 directly to this product*2. • To avoid the risk of accident and the potential violation of applicable laws, this product should never be used while the vehicle is being driven except for Navigation purposes. And, also Rear Displays should not be in a location where it is a visible distraction to the driver. • In some countries or states the viewing of images on a display inside a vehicle, even by persons other than the driver, may be illegal. Where such regulations apply, they must be obeyed, and this product’s rear video output features should not be used. Connecting the system - Connection diagram www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 272 1 2 3 4 1 2 3 4 C D F A B E Fuse holder Yellow To terminal always supplied with power regardless of ignition switch position. Red To electric terminal controlled by ignition switch (12 V DC) ON/OFF. Black (ground) To vehicle (metal) body. Orange/white To lighting switch terminal. Fuse resistor Fuse resistor For information on other leads With a 2 speaker system, do not connect anything to the speaker leads that are not connected to speakers. Blue To Auto-antenna relay control terminal. If the vehicle has a glass antenna, connect to the antenna booster power supply terminal (max. 300 mA 12 V DC). This product Note: Audio source will be set to mute or attenuate, while the voice guidance of the navigation will not be muted or attenuated. For details, see the “Operation Manual”. White White/black Gray Gray/black Green Green/black Violet Violet/black Front speaker Rear speaker Front speaker Rear speaker Left Right + ≠ + ≠ + ≠ + ≠ Note: When a subwoofer is connected to this product instead of a rear speaker, change the rear output setting in the Initial Setting. (Refer to the Operation Manual.) The subwoofer output of this product is monaural. Note: When connecting the blue lead to the auto antenna and using the auto antenna function, the vehicle’s antenna can be stowed by following the instructions below. - In the INITIAL menu, select “RADIO” for “AUTO ANTENNA” and change the source from radio to another source - Turn the source off - Turn off the ignition switch (ACC OFF) For more detailed information on changing the “AUTO ANTENNA” mode, refer to “Switching the auto antenna setting” in the “Operation Manual”. Yellow/black If you use equipment with a mute function (e.g. cellular telephones), connect that equipment to the Audio Mute lead. If not, keep the Audio Mute lead free of any connections. Note: Cords for this product and those for other products may be different colors even if they have the same function. When connecting this product to another product, refer to the supplied manuals of both prod- ucts and connect cords that have the same function. Connecting the power cord (1) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 273 5 6 7 8 5 6 7 8 C D F A B E Connecting the power cord (2) Pink (CAR SPEED SIGNAL INPUT) The mobile navigation system is connected here to detect the distance the vehicle travels. Always connect the vehicle’s speed detection circuit or the ND-PG1 speed pulse generator, sold separately. Failure to make this connection will increase errors in the location display. IMPROPER CONNECTION MAY RESULT IN SERIOUS DAMAGE OR INJURY INCLUDING ELECTRICAL SHOCK, VEHICLE’S ANTILOCK BRAKING SYSTEM, AUTOMATIC TRANSMISSION AND SPEEDOMETER INDICATION. LIGHT GREEN LEAD AT POWER CONNECTOR IS DESIGNED TO DETECT PARKED STATUS AND MUST BE CONNECTED TO THE POWER SUPPLY SIDE OF THE PARKING BRAKE SWITCH. IMPROPER CONNECTION OR USE OF THIS LEAD MAY VIOLATE APPLICABLE LAW AND MAY RESULT IN SERIOUS INJURY OR DAMAGE. Light green Used to detect the ON/OFF status of the parking brake. This lead must be connected to the power supply side of the parking brake switch. If this connection is made incorrectly or omitted, certain functions of your navigation system will be unusable. • It is strongly suggested that the speed pulse wire be connected • If the speed pulse wire is unavailable for some reason, it is recommended that the pulse generator (ND-PG1) be used. Notes: • The position of the speed detection circuit and the position of the parking brake switch vary depending on the vehicle model. For details, consult your authorized Pioneer dealer or an installation professional. • Even when the light green lead and the pink lead are connected correctly, a message indicating improper connection is shown until sensor initialization has completed. Be sure to use only the supplied extension lead. Use of another lead could cause fire, smoke and/or damage this product. Connection method Clamp the parking brake switch power supply side lead. lamp firmly with eedle-nosed pliers. Power supply side Ground side Parking brake switch Speed detection circuit lead Vehicle injection computer Connector Pass the extension cord and the lead for the speed detection circuit through this hole. Clamp firmly nosed pliers. Close the cover. Connection method Note: Cords for this product and those for other products may be different colors even if they have the same function. When connecting this product to another product, refer to the supplied manuals of both prod- ucts and connect cords that have the same function. Power cord Violet/white (REVERSEGEAR SIGNAL INPUT) This is connected so that the navigation system can detect whether the vehicle is moving forwards or backwards. Connect the violet/white lead to the lead whose voltage changes when the shift lever is put in reverse. Unless connected, the sensor may not detect your vehicle traveling forward/backward properly, and thus the position of your vehicle detected by the sensor may be misaligned from the actual position. When you use the ND-PG1 speed pulse switch to rear view camera picture. Connection method Clamp the reversing lamp lead. Clamp firmly with needle-nosed pliers. Reversing lamp lead Fuse resistor Check the position of your vehicle’s reversing lamp (the one that lights up when the shift lever is in reverse [R]) and find the reversing lamp lead in the trunk. This product Extension lead (for reverse signal) Extension lead (for speed signal) For information on other leads 5 m (16 ft. 5 in.) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 274 1 2 3 4 1 2 3 4 C D F A B E This product Front output (FRONT OUTPUT) Rear output (REAR OUTPUT) Power amp (sold separately) Power amp (sold separately) Power amp (sold separately) + ≠ + ≠ + ≠ + ≠ + ≠ + ≠ System remote control RCA cables (sold separately) Front speaker Rear speaker Subwoofer Front speaker Rear speaker Subwoofer Left Right 15 cm (5–7/8 in.) 23 cm (9 in.) Blue/white To system control terminal of the power amp (max. 300 mA 12 V DC). Do not connect this lead to Auto-antenna control terminal. 15 cm (5–7/8 in.) Perform these connections when using the optional amplifier. Subwoofer output or non-fading output (SUBWOOFER OUTPUT or NON-FANDING OUTPUT) When connecting to separately sold power amp www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 275 5 6 7 8 5 6 7 8 C D F A B E After Installing this product 1. Reconnecting the battery. First, double-check that all connections are correct and that this product is installed cor- the negative (–) cable to the negative (–) terminal of the battery. 2. Start the engine. 3. Press the RESET button on this product. Press the RESET button on this product using a pointed object such as the tip of a pen. 4. Enter the following settings: 1 2 Make any necessary installation angle adjustments. 4 Set the time and language. After installing this product, be sure to check in a safe place, that the vehicle is per- forming normally. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com AVIC-D1/UC 276 1 2 3 4 1 2 3 4 C D F A B E - Jigs List Name 45-Pin FFC 23-Pin BBR FFC 80-Pin FFC 20-Pin Extension Cord 30-Pin FFC 33-Pin FFC Monitor Adjustment PCB Test Disc Test Disc L.P.F. Test Disc Jig No. GGD1321 GGD1307 GGD1406 GGD1327 GGD1171 GGD1262 GGF1416 GGV1237 TCD-782 GGV1018 Remarks DVD Mechanism Module(MS3)(CN601) <--> CC Unit(CN2) ( )( ) ( ) CD Mechanism Module(S10.1)(CN901) <--> System Unit(CN1301) System Unit(CN1701) <--> CC Unit(CN605) System Unit(CN1802) <--> CC Unit(CN801) CC Unit(CN702) <--> Connector Unit(CN2804) CC Unit(CN701) <--> Monitor PCB(CN5002) For OSD display (*1) Operation check Checking the grating(CD) Checking the grating(Two pieces) Checking the grating(DVD) ( )( ) y ( ) y ( ) ( ) y ( ) ( ) ( ) ( ) y ( ) g g g( ) g g g g g g( ) Before shipping out the product, be sure to clean the following portions by using the prescribed cleaning tools: Portions to be cleaned Cleaning tools DVD, CD pickup lenses Cleaning liquid : GEM1004 Cleaning paper : GED-008 Portions to be cleaned Cleaning tools Fans Cleaning paper : GED-008 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com
