ORDER NO. PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A. PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936 PIONEER CORPORATION 2009 RRV4029 MULTI COMPACT DISC PLAYER PD-M426A PD-M406A THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S). This service manual should be used together with the following manual(s): For SPECIFICATIONS and PANEL FACILITIES, refer to the operating instructions. Model Type Power Requirement Remarks PD-M426A SYXJ5 AC 220 V to 240 V PD-M406A SYXJ5 AC 220 V to 240 V Model No. Order No. Remarks PD-M426/WYXJ/2 RRV1868 T-ZZZ. NOV. 2009 Printed in Japan www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com PD-M426A 2 1 2 3 4 1 2 3 4 C D F A B E SAFETY INFORMATION REAR This service manual is intended for qualified service technicians ; it is not meant for the casual do-it-yourselfer. Qualified technicians have the necessary test equipment and tools, and have been trainedto properly and safely repair complex products such as those covered by this manual. Improperly performed repairs can adversely affect the safety and reliability of the product and may void the warranty. If you are not qualified to perform the repair of this product properly and safely, you should not risk trying to do so and refer the repair to a qualified service technician. LASER DIODE CHARACTERISTICS MAXIMUM OUTPUT POWER : 7 mW WAVELENGTH : 780 to 785 nm IMPORTANT THIS PIONEER APPARATUS CONTAINS LASER OF CLASS 1. SERVICING OPERATION OF THE APPARATUS SHOULD BE DONE BY A SPECIALLY INSTRUCTED PERSON. Additional Laser Caution 1. Laser Interlock Mechanism The ON/OFF (ON : low level, OFF : high level) status of S601 (LPS1) and S602 (LPS2) switches for detecting the loading state is detected by the system microprocessor, and the design prevents laser diode oscillation except when both switches S601 and S602 are ON (low level or clamped state). Thus, interlock will no longer function if switches S601 (LPS1) and S602 (LPS2) are deliberately shorted (low level). The interlock also does not function in the test mode *. Laser diode oscillation will continue, if pin 33 of CXA1782CQ (IC151) on the MOTHER BOARD ASSY is connected to GND, or pin 50 of IC351 (LDON) is connected to low level (ON), or else the terminals of Q151 are shorted to each other (fault condition). 2. When the cover is opened with the servo mechanism block removed to be turned over, close viewing of the objective lens with the naked eye will cause exposure to a Class 1 laser beam. LABEL CHECK * : Refer to page 22 on the service manual RRV1868. PRW1622 Printed on the Rear Panel www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com PD-M426A 3 5 6 7 8 5 6 7 8 C D F A B E 1. CONTRAST OF MISCELLANEOUS PARTS 1.1 CONTRAST TABLE PD-M426/WYXJ/2, PD-M426A/SYXJ5 and PD-M406A/SYXJ5 are constructed the same except for the following: Mark No. Symbol and Description PD-M426/WYXJ/2 PD-M426A/SYXJ5 PD-M406A/SYXJ5 Remarks PCB ASSEMBLIES NSP 1..SUB BOARD Assy PWX1337 Not used Not used P7-19 2..FUNCTION BOARD Assy PWZ2769 Not used Not used NSP P7-34 2..SW BOARD Assy PWZ2805 Not used Not used 1..SUB BOARD Assy Not used PWX1689 PWX1688 P7-19 2..FUNCTION BOARD Assy Not used PWZ4184 PWZ4183 P7-34 2..SW BOARD Assy Not used PWZ4185 PWZ4185 > P7-20 1..MOTHER BOARD Assy PWM2156 PWM2380 PWM2379 > 1..TRANS Assy Not used PWM2378 PWM2378 No. 1 PACKING SECTION P5-1 Control Cable (for SR)(L=1 m) Not used Not used XDE3063 P5-2 Output Cable (for AUDIO)(L=1 m) PDE1248 XDE3047 XDE3047 P5-3 Remote Control Unit PWW1107 PWW1178 Not used P5-4 Battery Cover PZN1010 PZN1010 Not used P5-5 6-Compact Disc Magazine PXA1575 PXA1617 PXA1617 P5-6 Operating Instructions (De,It,NI,Sv,Es,Pt) PRD1018 Not used Not used P5-6 Operating Instructions (En,Fr) PRE1257 Not used Not used P5-9 CD Packing Case PHG2309 PHG2471 PHG2472 NSP P5-11 Dry Cell Battery (AAA/R03) VEM-022 VEM1049 Not used NSP P5-12 Warranty Card ARY7009 ARY7128 ARY7128 NSP Label(WEEE) Not used ARW7322 Not used IEC65-7 Caution Not used PRM1083 PRM1083 Eu Battery Caution Not used ARM7120 Not used Operating Instructions (En,Fr,De,It,NI,Es,Ru) Not used PRE1301 PRE1301 EXTERIOR SECTION P7-2 32P F.F.C/30V PDD1041 PDD1041 Not used P7-2 30P F.F.C/30V Not used Not used PDD1049 > P7-3 Power Transformer PTT1236 PTT1365 PTT1365 Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List. The mark found on some component parts indicates the importance of the safety factor of the part. Therefore, when replacing, be sure to use parts of identical designation. Screws adjacent to mark on product are used for disassembly. For the applying amount of lubricants or glue, follow the instructions in this manual. (In the case of no amount instructions, apply as you think it appropriate.) Nos. indicate the pages and Nos. in the service manual for the base model. NOTES: When ordering resistors, first convert resistance values into code form as shown in the following examples. Ex.1 When there are 2 effective digits (any digit apart from 0), such as 560 ohm and 47k ohm (tolerance is shown by J=5%, and K=10%). Ex.2 When there are 3 effective digits (such as in high precision metal film resistors). 5 6 1 4 7 3 R 5 0 1 R 0 RD1/4PU J RD1/4PU J RN2H K RS1P K 56 x 101 47 x 103 R50 1R0 561 473 RN1/4PC F 562 x 101 5621 5 2 6 1 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com PD-M426A 4 1 2 3 4 1 2 3 4 C D F A B E Notes:The number in the No. colume correspond to the number on “1.2 EXPLODED VIEWS”. For PCB assemblies, refer to “1.3 CONTRAST OF PCB ASSEMBLIES”, ”4. SCHEMATIC DIAGRAM” and “5. PCB CONNECTION DIAGRAM”. > P7-4 AC Power Cord PDG1003 VDG1061 VDG1061 P7-5 Bonnet PYY1149 PYY1299 PYY1299 P7-9 Function Panel PNW2726 PNW3069 PNW3070 P7-11 Name Plate PAM1608 PAM1776 PAM1776 P7-15 Display Window PAM1846 PAM1846 PAM1845 P7-21 Screw BBZ30P060FMC BBZ30P060FTC BBZ30P060FTC P7-22 Screw BBZ30P080FZK BBZ30P080FTC BBZ30P080FTC P7-23 Screw PPZ30P120FMC PPZ30P120FTC PPZ30P120FTC P7-24 Screw FBT40P080FZK FBT40P080FTB FBT40P080FTB P7-28 Screw PDZ30P050FMC PDZ30P050FTC PDZ30P050FTC NSP P7-30 Under Base PNA1751 PNA2650 PNA2650 P7-31 Rear Base PNA2413 PNA2648 PNA2649 P7-33 Flat Cable (6P) D20PYY0615E D20PYY0610E D20PYY0610E P7-35 LED Lens PNW2019 Not used Not used P7-38 Caution Label VRW1094 Not used Not used P7-39 Caution Label (HE) PRW1233 Not used Not used NSP P7-40 Locking Card Spacer PEC1036 Not used Not used P7-40 Locking Card Spacer Not used AEC7492 AEC7492 Barrier Not used PEC1053 PEC1053 No. 2 PCB Angle L Gc(fe) Not used PNB1670 PNB1670 No. 3 PCB Spacer Not used PEC1054 PEC1054 No. 4 Rivet Not used AEC7514 AEC7514 No. 5 Screw Spacer Not used PEB1349 PEB1349 No. 6 Screw Not used BBZ30P040FCC BBZ30P040FCC No. 7 Screw Not used BBZ30P060FTC BBZ30P060FTC No. 8 Mark No. Symbol and Description PD-M426/WYXJ/2 PD-M426A/SYXJ5 PD-M406A/SYXJ5 Remarks www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com PD-M426A 5 5 6 7 8 5 6 7 8 C D F A B E A B C D E F C A B B A A B D E F D D No .2 No. 5 No. 5 No. 8 No .8 No. 7 No. 7 No. 7 No. 3 No. 3 No. 3 No. 6 No. 6 No. 6 No. 4 No. 4 No. 1 E F A H F F F F Locking Card Spacer PEC1036 1.2 EXPLODED VIEWS www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com PD-M426A 6 1 2 3 4 1 2 3 4 C D F A B E 1.3 CONTRAST OF PCB ASSEMBLIES AF MOTHER BOARD Assy PWM2156, PWM2380 and PWM2379 are constructed the same except for the following: *1 : Refer to “3. SCHEMATIC DIAGRAM” (C-7) on the service manual RRV1868. EF FUNCTION BOARD Assy PWZ2769, PWZ4184 and PWZ4183 are constructed the same except for the following: FF SW BOARD Assy PWZ2805, PWZ4185 and PWZ4185 are constructed the same except for the following: Mark Symbol and Description PWM2156 PWM2380 PWM2379 Remarks > Rapping Terminal RKC-061 Not used Not used > J0 2P Connector Assy Not used PKP1029 PKP1029 D392, D393, D394 Not used Not used 1SS254 *1 L391 Not used Not used LAU1R0J *1 CN351 32P FFC CONNECTOR HLEM32S-1 HLEM32S-1 Not used CN351 30P FFC CONNECTOR Not used Not used HLEM30S-1 JA391, J392 SR JACK Not used Not used RKN1004 *1 R52, R53, R54 RD1/4PU152J RD1/4PU182J RD1/4PU182J R362, R363 RD1/4PU103J Not used Not used R391 Not used Not used RD1/4PU244J *1 R392 Not used Not used RD1/4PU102J *1 C393 Not used Not used CCCSL101J50 *1 C399 Not used Not used CKCYF103Z50 *1 Mark Symbol and Description PWZ2769 PWZ4184 PWZ4183 Remarks J0 Connector Assy Not used PF04PG-C12 PF04PG-C12 CN701 32P FFC CONNECTOR 9607S-32F 9607S-32F Not used CN701 30P FFC CONNECTOR Not used Not used 9607S-30F Remote Sensor SBX1976-51 SBX1976-51 Not used Mark Symbol and Description PWZ2805 PWZ4185 Remarks J801 D20PWW0420E PF02PG-C27 D801 LED PCX1019 Not used www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com PD-M426A 7 5 6 7 8 5 6 7 8 C D F A B E 1.4 PCB PARTS LIST Mark No. Circuit Symbol and No. Part No. HF TRANS ASSY SEMICONDUCTORS IC901,906 TC7WH123FU > IC902 NJM78M05FA IC903,907 TC74VHCU04FT IC904 TC7W74FU IC905 TC74VHC125FTS1 IC909 TC74VHC08FTS1 Q901,902,904,906 LTC124EUB Q903,905 RN4903 D901,902,904-906 1SS355 > D907 S1VB60 MISCELLANEOUS KN901 WRAPPING TERMINAL VNF1084 > RY901 JOE LOWPOWER RELAY ASR7013 > T801 POWER TRANSFORMER ATT7078 > CN810 AC CODE SOCKET RKP1751 > CN811 AMP U-P CONNECTOR RKP1834 CN902 PLUG(2P) KM200NA2 CN904 6P JUMPER CONNECTOR 52147-0610 CN905 PLUG(4P) KM200NA4 JH901 6P CABLE HOLDER 51048-0600 JH902 PCB BINDER VEF1040 JP901 JUMPER WIRE D20PYY0610E RESISTORS R903 RD1/4MUF220J Other Resistors RS1/10SR###J CAPACITORS > C820 ACE7013 C902,903,907,908 CKSRYB104K16 C904 CEAT102M25 C905 CEAT221M16 C906,909,920 CKSRYB105K10 C910,913,917-919 CKSRYB104K16 C912 CEAT330M16 C915 CKSRYB103K25 C921,923,924 CKSRYB104K16 C922 CEAT470M10 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com PD-M426A 8 1 2 3 4 1 2 3 4 C D F A B E 2. DIFFERENCE FROM PD-M426 2.1 CONNECTION DIAGRAM CONNECTION DIAGRAM SECONDARY part POWER Circuit MAIN TRANS uCOM FL Grid, Segment Different part (Added part) KEY MATRIX POWER MULTI MECHANISM ASSY Partial SG output with port SUB TRANS AC Relay Relay Control Circuit VDG1061 RKP1751 RKP1834- PF04PG-C12 (2p) (4p) D20PYY 0610E D20PYY 0610E PF02PG-C27 F A F H F E F F www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com PD-M426A 9 5 6 7 8 5 6 7 8 C D F A B E OPERATION MODE DIFFERENCE PD-M426 6 magazine/Single magazine 6 magazine Single magazine about 5 W Used Used from OFF e d o m y b d n a t S ) e niz a g a m t u o h ti w ( ni g ulp C A ) n o C S I D fi Y A L P ( N O ) e niz a g a m h ti w ( ni g ulp C A from standby mode T C E J E r e tf a e d o m y b d n a t S n oit a r e p o T C E J E N O ) e niz a g a m t u o h ti w ( y e k r e w o p tin u nia M N O ) e niz a g a m h ti w ( y e k r e w o p tin u nia M Remote control power key (without magazine ON Remote control power key (with magazine) ON Power ON by SR control (without magazine) ON N O ) e niz a g a m h ti w ( lo rt n o c R S y b N O r e w o P N O e niz a g a m e h t g nid a o L from ON e d o m y b d n a t S y e k r e w o p tin u nia M e d o m y b d n a t S y e k r e w o p lo rt n o c e t o m e R e d o m y b d n a t S lo rt n o c R S y b F F O r e w o P d e s u n oitc n u f e m u s e R n oitc n u F y r o m e M from TR1 of the last played DISC d e s u t o N T A E P E R d e s u t o N M A D N A R d e s U M A R G O R P PD-M426A/PD-M406A Standby power consumption 0.3 W Remote control power key Not used Standby LED Not used Standby mode ON (Play if DISC on) No operation ON ON (Play if DISC on) No operation No operation No operation No operation No operation Standby mode No operation by accessory remote control unit Standby mode by using preset remote control unit Not used Standby mode Not used from TR1 of DISC1 after power on (State recovery when rebooting the unit ) Not used Not used 2.2 OPERATION MODE DIFFERENCE www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com PD-M426A 10 1 2 3 4 1 2 3 4 C D F A B E 3. LOGIC WAVEFORM OF TRANS ASSY Logic waveform with loading the magazine Note : The numbers in framed rectangle denote measuring point in the schematic diagram. TRANS Assy each part logic waveform with loading the magazine Each logic is 5V operation. Standby switch ON (AC primary relay OFF operation) AC plug in (AC primary relay ON operation) 18 5 6 7 8 9 10 13 17 AC primary relay ON 1 2 3 4 11 12 AC primary relay OFF AC primary relay OFF 16 Standby switch ON (AC primary relay ON operation) AC primary relay ON Power OFF by SR or smart remote control (AC primary relay OFF operation) 14 15 30ms 80ms 200ms 300us 200ms 300us 200ms 300us 100ms 100ms 100ms www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com PD-M426A 11 5 6 7 8 5 6 7 8 C D F A B E TRANS Assy each part logic waveform without loading the magazine Each logic is 5V operation. 18 5 6 7 8 9 10 16 13 Standby switch ON (AC primary relay OFF operation) Standby switch ON (AC primary relay ON operation) 4 11 1 2 3 AC plug in (AC primary relay OFF state) u-com communication time 14 15 12 17 AC primary relay OFF AC primary relay ON AC primary relay OFF Standby switch ON (AC primary relay ON operation) AC primary relay ON u-com communication time Power OFF by SR or smart remote control (AC primary relay OFF operation) AC primary relay OFF 30ms 80ms 300us 200ms 200ms 300us 200ms 100ms 200ms 200ms 100ms 300us Logic waveform without loading the magazine Note : The numbers in framed rectangle denote measuring point in the schematic diagram. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com PD-M426A 12 1 2 3 4 1 2 3 4 C D F A B E H designation. with same parts (safety regulation authorized) of identical mark found on some component parts should be replaced The pwm2378- Sub Ass'y No: ! ! ! ! ! ! ! ! C820 ACE7013-A T801 ATT7078-A 1 2 3 4 5 6 7 8 9 ASR7013-A RY901 1 1 2 2 3 3 4 4 D901 1SS355 D902 1SS355 R903 22 RD1/4MUF220J-T LTC124EUB Q901 2 3 1 GNDD CN902 KM200NA2 1 V+5 2 POWER 1000u/25 C904 NJM78M05FA IC902 1 OUT 2 GND 3 IN 220u/16 C905 C907 0.1u/16 V+5 GNDD LTC124EUB Q902 2 3 1 R908 4.7k V+5 GNDD C902 0.1u/16 V+5 V+5 GNDD R901 470 R902 33 C903 0.1u/16 GNDD TC7WH123FU IC901 A 1 B 2 CLR 3 GND 4 5 Q 6 Cx 7 Rx/Cx 8 VCC GNDD C908 0.1u/16 R904 220k C906 1u/10 D904 1SS355 GNDD R905 33 PWT TCT 33u/16 C912 C913 0.1u/16 R912 47k R911 2.2k R917 NM V+5 GNDD GNDD GNDD IC905 TC74VHC125FTS1 1 G 2 A 3 Y 14 VCC 7 GND GNDD V+5 GNDD C917 0.1u/16 C918 0.1u/16 GNDD V+5 GNDD R910 33 R906 33 R913 33 C909 1u/10 GNDD TCT R907 33 TCT R916 1k R914 4.7k D905 1SS355 CLR GNDD RN4903 Q903 6 2 1 RN4903 Q903 3 5 4 V+5 GNDD R919 4.7k R915 NM IC903 TC74VHCU04FT 2 Y 1 A 7 GND 14 VCC IC903 TC74VHCU04FT 6 Y 5 A 7 GND 14 VCC IC903 TC74VHCU04FT 4 Y 3 A 7 GND 14 VCC IC903 TC74VHCU04FT 8 Y 9 A 7 GND 14 VCC V+5 C910 0.1u/16 GNDD GNDD R918 470 VNF1084-A KN901 1 GNDD GNDC R947 0 RKP1751-A CN810 1 L 2 N RKP1834-A CN811 1 N 2 L R948 33 D908 NM VEF1040-A JH902 R949 0 C821 NM C915 0.01u/25 D907 S1VB60 1 2 4 3 TC7W74FU IC904 CK 1 D 2 Q 3 GND 4 5 Q 6 CLR 7 PR 8 VCC L N AC CABLE RS1/10SR***J CKSRYB*** CEAT*** SSOP8 P-0.65 TSSOP14 P-0.65 LEAD TYPE UMD2 UMT3F or US6 RESISTOR CAPACITOR DIODE TRANSISTOR 14PIN IC 8PIN IC LEAD TYPE NOTE F A F 1 2 11 8 13 10 12 14 9 4. SCHEMATIC DIAGRAM 4.1 TRANS ASSY www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com PD-M426A 13 5 6 7 8 5 6 7 8 C D F A B E H R917 NM C919 0.1u/16 GNDD TC7WH123FU IC906 A 1 B 2 CLR 3 GND 4 5 Q 6 Cx 7 Rx/Cx 8 VCC V+5 R922 100k D906 1SS355 GNDD C920 1u/10 GNDD C921 0.1u/16 POW 52147-0610 CN904 1 MZS1M 2 MZS2M 3 DCHM 4 DCNT 5 DSEL 6 GNDM V+5 R937 4.7k V+5 R939 4.7k SW2 SW1 R940 33 R941 33 R943 4.7k R944 4.7k IC905 TC74VHC125FTS1 10 G 9 A 8 Y 14 VCC 7 GND IC905 TC74VHC125FTS1 13 G 12 A 11 Y 14 VCC 7 GND 5FTS1 IC905 TC74VHC125FTS1 4 G 5 A 6 Y 14 VCC 7 GND GNDD GNDD GNDD GNDD 51048-0600 JH901 1 MZS1 2 MZS2 3 DCHM 4 DCNT 5 DSEL 6 GNDM SW1 SW2 R924 33 R925 NM R933 33 R932 33 SW1 R927 33 SW2 R926 33 R931 33 R936 33 TCT POW R935 33 GNDD RN4903 Q905 6 2 1 PWT RN4903 Q905 3 5 4 V+5 GNDD V+5 GNDD C923 0.1u/16 GNDD GNDD V+5 C924 0.1u/16 LTC124EUB Q906 2 3 1 CN905 KM200NA4 1 KD0 2 SE 3 GNDD 4 STBL R945 470 R946 470 GNDD GNDD CLR R920 4.7k LTC124EUB Q904 2 3 1 GNDD 47u/10 C922 GNDD GNDD R929 4.7k IC903 TC74VHCU04FT 12 Y 13 A 7 GND 14 VCC IC903 TC74VHCU04FT 10 Y 11 A 7 GND 14 VCC IC907 TC74VHCU04FT 2 Y 1 A 7 GND 14 VCC IC907 TC74VHCU04FT 4 Y 3 A 7 GND 14 VCC IC907 TC74VHCU04FT 6 Y 5 A 7 GND 14 VCC IC907 TC74VHCU04FT 10 Y 11 A 7 GND 14 VCC IC907 TC74VHCU04FT 8 Y 9 A 7 GND 14 VCC IC907 TC74VHCU04FT 12 Y 13 A 7 GND 14 VCC GNDD GNDD IC909 TC74VHC08FTS1 3 1 2 14 7 IC909 TC74VHC08FTS1 6 4 5 14 7 IC909 TC74VHC08FTS1 8 9 10 14 7 IC909 TC74VHC08FTS1 11 12 13 14 7 R928 2.2k R960 0 GNDD JP901 D20PYY0610E H TRANS ASSY(PWM2378) CN602 D CN204 A E F F 6 7 3 16 5 15 4 17 18 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com PD-M426A 14 1 2 3 4 1 2 3 4 C D F A B E H SIDE A H TRANS ASSY PNP1498-A NOTE FOR PCB DIAGRAMS : 1. The parts mounted on this PCB include all necessary parts for several destinations. For further information for respective desti- nations, be sure to check with the sche- matic diagram. Capacitor Connector P.C.Board Chip Part SIDE A SIDE B 2. View point of PCB diagrams. PWM2378 PWM TRANS ASSY N N L L YELLOW WHITE PRIMARY SECONDARY /4 1 MZS1 2 MZS2 3 DCHM 4 DCNT 5 DSEL 6 GNDM 6 1 6 GNDM 5 DSEL 4 DCNT 3 DCHM 2 MZS2M 1 MZS1M STBL GNDD SE KD0 1 4 1 V+5 2 POWER GNDD GNDD GNDD V+5 V+5 POW V+5 V+5 V+5 V+5 V+5 POW GNDD GNDD GNDD GNDD B C A + - CN810 CN811 KN901 C820 T801 J921 J919 J922 J918 J916 J917 J920 J915 R903 J912 J910 J911 J914 J923 J909 J908 J907 J906 CN902 J903 J905 CN904 J904 CN905 C904 C905 C912 C922 RY901 D907 IC902 JH901 C7 [[ G ]] LF JH902 J951 J952 PC C821 J913 D CN602 A CN204 E J801 F IC902 IC Q 1 1 1 1 5 1 1 5 1 1 1 1 1 5 1 F F 5. PCB CONNECTION DIAGRAM 5.1 TRANS ASSY www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com PD-M426A 15 5 6 7 8 5 6 7 8 C D F A B E H Q901 Q902 Q903 Q904 Q905 Q906 IC901 IC903 IC904 IC905 IC906 IC907 IC909 IC Q SIDE B H TRANS ASSY PNP1498-A SECONDARY PRIMARY KD0 SE GNDD STBL GNDM DSEL DCNT DCHM MZS2 MZS1 MZS1M MZS2M 1 1 6 6 2 POWER 1 V+5 1 2 Q901 Q902 Q903 Q904 Q905 Q906 R901 R902 R904 R905 R906 R907 R908 R910 R911 R912 R913 R914 R915 R916 R917 R918 R919 R920 R922 R924 R925 R926 R927 R928 R929 R931 R932 R933 R935 R936 R937 R939 C902 C903 R940 R941 C906 C907 R943 C908 R944 C909 R945 R946 R947 R948 C910 C913 C915 C917 C918 C919 C920 C921 C923 C924 D901 D902 D904 D905 D906 D908 IC901 14 7 IC903 IC904 7 14 IC905 IC906 14 7 IC907 7 14 IC909 R949 R960 LF E E 1 E 1 E 1 5 1 5 10 1 5 1 5 1 5 1 5 10 1 5 10 F F www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com
