ORDER NO. PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A. PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936 PIONEER CORPORATION 2008 ND-G500/XS/E5 CRT4156 4-CHANNEL GATEWAY AMPLIFIER ND-G500/XS/E5 For details, refer to "Important Check Points for Good Servicing". K-ZZZ. APR. 2008 Printed in Japan www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com ND-G500/XS/E5 2 1 2 3 4 1 2 3 4 C D F A B E SAFETY INFORMATION This service manual is intended for qualified service technicians; it is not meant for the casual do-it-yourselfer. Qualified technicians have the necessary test equipment and tools, and have been trained to properly and safely repair complex products such as those covered by this manual. Improperly performed repairs can adversely affect the safety and reliability of the product and may void the warranty. If you are not qualified to perform the repair of this product properly and safely, you should not risk trying to do so and refer the repair to a qualified service technician. Where in a manufacturer’s service documentation, for example in circuit diagrams or lists of components, a symbol is used to indicate that a specific component shall be replaced only by the component specified in that documentation for safety reasons, the following symbol shall be used: > www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com ND-G500/XS/E5 3 5 6 7 8 5 6 7 8 C D F A B E [Important Check Points for Good Servicing] In this manual, procedures that must be performed during repairs are marked with the below symbol. Please be sure to confirm and follow these procedures. 1. Product safety Please conform to product regulations (such as safety and radiation regulations), and maintain a safe servicing environment by following the safety instructions described in this manual. 1 Use specified parts for repair. Use genuine parts. Be sure to use important parts for safety. 2 Do not perform modifications without proper instructions. Please follow the specified safety methods when modification(addition/change of parts) is required due to interferences such as radio/TV interference and foreign noise. 3 Make sure the soldering of repaired locations is properly performed. When you solder while repairing, please be sure that there are no cold solder and other debris. Soldering should be finished with the proper quantity. (Refer to the example) 4 Make sure the screws are tightly fastened. Please be sure that all screws are fastened, and that there are no loose screws. 5 Make sure each connectors are correctly inserted. Please be sure that all connectors are inserted, and that there are no imperfect insertion. 6 Make sure the wiring cables are set to their original state. Please replace the wiring and cables to the original state after repairs. In addition, be sure that there are no pinched wires, etc. 7 Make sure screws and soldering scraps do not remain inside the product. Please check that neither solder debris nor screws remain inside the product. 8 There should be no semi-broken wires, scratches, melting, etc. on the coating of the power cord. Damaged power cords may lead to fire accidents, so please be sure that there are no damages. If you find a damaged power cord, please exchange it with a suitable one. 9 There should be no spark traces or similar marks on the power plug. When spark traces or similar marks are found on the power supply plug, please check the connection and advise on secure connections and suitable usage. Please exchange the power cord if necessary. a Safe environment should be secured during servicing. When you perform repairs, please pay attention to static electricity, furniture, household articles, etc. in order to prevent injuries. Please pay attention to your surroundings and repair safely. 2. Adjustments To keep the original performance of the products, optimum adjustments and confirmation of characteristics within specification. Adjustments should be performed in accordance with the procedures/instructions described in this manual. 4. Cleaning For parts that require cleaning, such as optical pickups, tape deck heads, lenses and mirrors used in projection monitors, proper cleaning should be performed to restore their performances. 3. Lubricants, Glues, and Replacement parts Use grease and adhesives that are equal to the specified substance. Make sure the proper amount is applied. 5. Shipping mode and Shipping screws To protect products from damages or failures during transit, the shipping mode should be set or the shipping screws should be installed before shipment. Please be sure to follow this method especially if it is specified in this manual. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com ND-G500/XS/E5 4 1 2 3 4 1 2 3 4 C D F A B E CONTENTS SAFETY INFORMATION..................................................................................................................................... 2 1. SERVICE PRECAUTIONS............................................................................................................................... 5 1.1 SERVICE PRECAUTIONS ........................................................................................................................ 5 1.2 NOTES ON SOLDERING .......................................................................................................................... 5 2. SPECIFICATIONS............................................................................................................................................ 6 2.1 SPECIFICATIONS ..................................................................................................................................... 6 2.2 CONNECTION DIAGRAM ......................................................................................................................... 7 3. BASIC ITEMS FOR SERVICE.......................................................................................................................... 8 3.1 CHECK POINTS AFTER SERVICING....................................................................................................... 8 4. BLOCK DIAGRAM............................................................................................................................................ 9 5. DIAGNOSIS...................................................................................................................................................... 9 5.1 TROUBLESHOOTING............................................................................................................................... 9 5.2 CONNECTOR FUNCTION DESCRIPTION............................................................................................... 9 6. SERVICE MODE .............................................................................................................................................. 9 7. DISASSEMBLY .............................................................................................................................................. 10 8. EACH SETTING AND ADJUSTMENT ............................................................................................................11 9. EXPLODED VIEWS AND PARTS LIST...........................................................................................................11 9.1 PACKING ..................................................................................................................................................11 9.2 EXTERIOR............................................................................................................................................... 12 10. SCHEMATIC DIAGRAM............................................................................................................................... 14 10.1 AMP UNIT(GUIDE PAGE) ..................................................................................................................... 14 11. PCB CONNECTION DIAGRAM.................................................................................................................... 20 11.1 AMP UNIT .............................................................................................................................................. 20 12. ELECTRICAL PARTS LIST .......................................................................................................................... 24 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com ND-G500/XS/E5 5 5 6 7 8 5 6 7 8 C D F A B E 1. SERVICE PRECAUTIONS 1.1 SERVICE PRECAUTIONS 1.2 NOTES ON SOLDERING 1. You should conform to the regulations governing the product (safety, radio and noise, and other regulations), and should keep the safety during servicing by following the safety instructions described in this manual. 2. Be careful in handling ICs. Some ICs such as MOS type are so fragile that they can be damaged by electrostatic induction. 3. The area where the temperature gets high as a completely assembled product is the heat sink. As a unit, on the other hand, sub-heat sink and the periphery of the sub-heat sink are the areas where the temperature gets high. 4. Approximately one hour after activating, the temperature on part of outer surface reaches nearly 70 oC. Therefore, be careful not to get burn, immediately after turning off power. 5. Watch out for a hot heat sink. Operations while removing a heat sink can cause failure. 6. As a heat sink (approx. 250 g to 300 g) is heavy comparing with the product weight (approx. 900 g). Keep a balance when taking out the board. For environmental protection, lead-free solder is used on the printed circuit boards mounted in this unit. Be sure to use lead-free solder and a soldering iron that can meet specifications for use with lead-free solders for repairs accompanied by reworking of soldering. Compared with conventional eutectic solders, lead-free solders have higher melting points, by approximately 40 C. Therefore, for lead-free soldering, the tip temperature of a soldering iron must be set to around 373 C in general, although the temperature depends on the heat capacity of the PC board on which reworking is required and the weight of the tip of the soldering iron. Compared with eutectic solders, lead-free solders have higher bond strengths but slower wetting times and higher melting temperatures (hard to melt/easy to harden). The following lead-free solders are available as service parts: Parts numbers of lead-free solder: GYP1006 1.0 in dia. GYP1007 0.6 in dia. GYP1008 0.3 in dia. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com ND-G500/XS/E5 6 1 2 3 4 1 2 3 4 C D F A B E 2. SPECIFICATIONS 2.1 SPECIFICATIONS www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com ND-G500/XS/E5 7 5 6 7 8 5 6 7 8 C D F A B E 2.2 CONNECTION DIAGRAM www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com ND-G500/XS/E5 8 1 2 3 4 1 2 3 4 C D F A B E 3. BASIC ITEMS FOR SERVICE 3.1 CHECK POINTS AFTER SERVICING To keep the product quality after servicing, please confirm following check points. d e m rif n o c e b o t m e tI s e r u d e c o r P . o N 1 Confirm whether the customer complain has been solved. The customer complain must not be reappeared. Audio and operations must be normal. 2 Check the output sound. Audio and operations must be normal. r e tf a e c n a r a e p p a sti n o trid r o s e h ct a r c s o N k c e h c e c n a r a e p p A 3 receiving it for service. See the table below for the items to be checked regarding video and audio: Item to be checked regarding audio Distortion Noise Volume too low Volume too high Volume fluctuating Sound interrupted www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com ND-G500/XS/E5 9 5 6 7 8 5 6 7 8 C D F A B E 4. BLOCK DIAGRAM There is not information to be shown in this chapter. 5. DIAGNOSIS 5.1 TROUBLESHOOTING 5.2 CONNECTOR FUNCTION DESCRIPTION 6. SERVICE MODE There is not information to be shown in this chapter. Output audio from the Speaker is switched by “AMP control terminal” (Blue/white cable) If the terminal signal is “L”, the audio from Mini-plug (AVIC-F500BT) is selected. If the terminal signal is “H”, Car stereo audio is selected. Please see following table for more detail. Output Audio from AMP Control terminal (Blue/White) Inside of a product Car stereo AVIC-F500BT H L L H L H L L Q790 - Base (CONT2) IC220, 250 2pin (CNT1) IC220, 250 4pin (CNT2) AUDIO INPUT 1. CNT 2. NC 3. GND 4. NC 5. 5V 1. FL-OUT 2. FL-IN 3. FL+OUT 4. FL+IN 5. FR-OUT 6. FR-IN 7. FR+OUT 8. FR+IN 9. RR+OUT 10. RR+IN 11. RR-OUT 12. RR-IN 13. RL+OUT 14. RL+IN 15. RL-OUT 16. RL-IN 17. ACC 18. GND 19. BUP 20. GND 1 1 19 5 2 20 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com ND-G500/XS/E5 10 1 2 3 4 1 2 3 4 C D F A B E 7. DISASSEMBLY ND-G500/XS/E5 Case 1 1 Fig.1 Fig.2 Removing the Case (Fig.1) Removing the Amp Unit (Fig.2) Remove the eight screws and then remove the Case. Heat Sink Chassis Heat Sink Chassis Amp Unit 2 2 2 1 1 1 1 2 2 1 1 Remove the six screws and then separate the Heat Sink and the Chassis. 2 Remove the five screws and then remove the Amp Unit. 1 1 1 1 1 1 1 1 (Caution) 1) Approximately one hour after activating, the temperature on part of outer surface reaches nearly 70 oC. Therefore, be careful not to get burn, immediately after turning off power. 2) Watch out for a hot heat sink. Operations while removing a heat sink can cause failure. 3) As a heat sink (approx. 250 g to 300 g) is heavy comparing with the product weight (approx. 900 g). Keep a balance when taking out the board. (Note) While fixing a heat sink to a chassis, Amp Unit cannot be removed. Meanwhile, even if screws are taken out, the heat sink is not removed from the chassis. (The heat sink is removed together with Amp Unit. They cannot be removed separately.) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com ND-G500/XS/E5 11 5 6 7 8 5 6 7 8 C D F A B E 8. EACH SETTING AND ADJUSTMENT There is not information to be shown in this chapter. 9. EXPLODED VIEWS AND PARTS LIST 9.1 PACKING PACKING SECTION PARTS LIST NOTES : Parts marked by " * " are generally unavailable because they are not in our Master Spare Parts List. The > mark found on some component parts indicates the importance of the safety factor of the part. Therefore, when replacing, be sure to use parts of identical designation. Screw adjacent to mark on the product are used for disassembly. For the applying amount of lubricants or glue, follow the instructions in this manual. (In the case of no amount instructions,apply as you think it appropriate.) " Mark No. Description Part No. 1 Cord Assy CDP1133 2 Cord Assy CDP1140 3 Polyethylene Bag CEG1116 4 Fastener CNM3728 5 Fastener CNM3729 6 Owner's Manual CRD4344 (English, Spanish, German, French, Italian, Dutch, Russian) 7 Air Cushioned Bag CEG1007 8 Unit Box CHG6544 9 Contain Box CHL6544 Mark No. Description Part No. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com ND-G500/XS/E5 12 1 2 3 4 1 2 3 4 C D F A B E 9.2 EXTERIOR ND-G500/XS/E5 A A A www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com ND-G500/XS/E5 13 5 6 7 8 5 6 7 8 C D F A B E EXTERIOR SECTION PARTS LIST Mark No. Description Part No. 1 Cord Assy CDP1133 > 2 Fuse(10 A) CEK1136 3 Cap CNS1472 4 Resistor RS1/2PMF102J 5 Screw ASZ26P050FTC 6 Screw BSZ26P060FTB 7 Screw BSZ26P160FTC 8 Chassis CNA3074 9 Case CNB3511 10 Insulator CNN2375 11 Heat Sink CNR1962 12 Plug(CN700) CKM1132 13 Holder CND4613 14 Holder CND4614 15 Holder CND4694 16 Connector(JA700) CKM1438 17 Connector(JA270) CKS4124 18 IC(IC700) PAL007C 19 Sheet CNN2464 20 Sheet CNN2466 21 Sheet CNN2465 22 Amp Unit CWN3555 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com ND-G500/XS/E5 14 1 2 3 4 1 2 3 4 C D F A B E 10. SCHEMATIC DIAGRAM 10.1 AMP UNIT(GUIDE PAGE) A A-a A-a A-b A-a A-b A-b A-a Large size SCH diagram Guide page Detailed page Note: When ordering service parts, be sure to refer to " EXPLODED VIEWS AND PARTS LIST" or "ELECTRICAL PARTS LIST". > www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com ND-G500/XS/E5 15 5 6 7 8 5 6 7 8 C D F A B E A A-b 7u CTH1381 The > mark found on some component parts indicates the importance of the safety factor of the part. Therefore, when replacing, be sure to use parts of identical designation. Symbol indicates a resistor. No differentiation is made between chip resistors and discrete resistors. NOTE : Symbol indicates a capacitor. No differentiation is made between chip capacitors and discrete capacitors. A AMP UNIT www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com ND-G500/XS/E5 16 1 2 3 4 1 2 3 4 C D F A B E A-a A-b A-b A AMP UNIT www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com ND-G500/XS/E5 17 5 6 7 8 5 6 7 8 C D F A B E A-a A-b A-b 7u CTH1381 The > mark found on some component parts indicates the importance of the safety factor of the part. Therefore, when replacing, be sure to use parts of identical designation. Symbol indicates a resistor. No differentiation is made between chip resistors and discrete resistors. NOTE : Symbol indicates a capacitor. No differentiation is made between chip capacitors and discrete capacitors. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com ND-G500/XS/E5 18 1 2 3 4 1 2 3 4 C D F A B E A-b A-a A-a A-b www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com ND-G500/XS/E5 19 5 6 7 8 5 6 7 8 C D F A B E A-a A-b A-b A-a > www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com ND-G500/XS/E5 20 1 2 3 4 1 2 3 4 C D F A B E 11. PCB CONNECTION DIAGRAM 11.1 AMP UNIT A A AMP UNIT Capacitor Connector P.C.Board Chip Part SIDE B SIDE A NOTE FOR PCB DIAGRAMS 1.The parts mounted on this PCB include all necessary parts for several destination. For further information for respective destinations, be sure to check with the schematic dia- gram. 2.Viewpoint of PCB diagrams 5 1 10 1 5 10 15 5 1 10 E 1 5 10 15 5 1 10 E 1 1 1 E E 1 1 E E 1 5 E R210 R211 R212 R213 R214 D761 R230 R231 R232 R233 R234 C200 C202 C204 R240 R241 R242 R243 R244 C210 C212 C214 D790 C215 C220 2 2 2 C 1 2 2 C C223 C225 C226 C227 C228 C229 R841 R842 C230 C232 C234 R270 R271 R275 R276 C240 C242 C244 R280 R281 C245 R285 C250 2 5 2 C 1 5 2 C C253 C254 JA270 C255 C256 C257 C258 D200 D202 Q300 Q301 Q302 C842 Q303 D210 C270 C271 C272 D212 Q310 Q311 C275 Q312 C276 Q313 C277 C278 IC200 C280 C281 C285 C286 D230 D232 D240 IC220 D242 IC230 L720 Q740 R300 R301 R302 R303 R304 R305 IC250 D270 R310 R311 R312 R3 R314 R315 D280 L750 D285 IC270 CN700 C300 C301 C302 C303 Q790 Q791 C310 C311 C312 C313 C7 R740 R741 R742 L790 R761 R762 C740 C741 C742 C746 C747 C749 C750 C751 C752 C753 C754 R790 R791 C755 C756 R792 R793 C759 C760 FU281 C761 C790 R200 D740 R201 D742 R202 R203 R204 10 20 30 40 50 60 70 X 100 90 80 70 60 50 40 30 20 10 0 Y C762 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com ND-G500/XS/E5 21 5 6 7 8 5 6 7 8 C D F A B E A SIDE A 1 5 E E E E E E E E 5 1 5 1 20 10 1 5 10 15 20 25 5 D770 IC770 29 00 02 C282 C283 C285 C286 C287 C289 Q710 FU770 Q713 L700 C290 C291 C292 C293 C294 C295 C296 C297 C298 Q723 Q725 Q730 Q733 R303 R312 R313 R320 R710 R711 R712 R713 R714 Q775 Q776 R720 JA700 R721 R722 R723 R724 L770 R725 L771 R726 L772 R727 L773 R728 R729 R730 R731 R732 R733 R734 R735 R736 C700 C701 C702 C705 C706 C320 C713 C725 C730 C731 R771 R772 R773 R774 R775 R776 R777 R778 R779 R785 D700 C763 C764 C765 D320 D321 C770 D710 D711 C771 C772 C773 C774 C775 C776 C777 C778 C779 IC700 D720 C780 D721 C785 R200 70 80 90 100 110 120 130 140 150 160 C284 C288 C299 FRONT FU 770 (A,138,20) Fuse 4 A CEK1260 > www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com ND-G500/XS/E5 22 1 2 3 4 1 2 3 4 C D F A B E A A AMP UNIT 160 150 140 130 120 110 100 90 1 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com ND-G500/XS/E5 23 5 6 7 8 5 6 7 8 C D F A B E A SIDE B 90 80 70 60 50 40 30 20 X 100 90 80 70 60 50 40 30 20 10 0 Y 10 1 1 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com ND-G500/XS/E5 24 1 2 3 4 1 2 3 4 C D F A B E 12. ELECTRICAL PARTS LIST NOTE: Parts whose parts numbers are omitted are subject to being not supplied. The part numbers shown below indicate chip components. Chip Resistor RS1/_S___J,RS1/__S___J Chip Capacitor (except for CQS.....) CKS....., CCS....., CSZS..... The > mark found on some component parts indicates the importance of the safety factor of the part. Therefore, when replacing, be sure to use parts of identical designation. Meaning of the figures and others in the parentheses in the parts list. Example) IC 301 is on the point (face A, 91 of x-axis, and 111 of y-axis) of the corresponding PC board. IC 301 (A, 91, 111) IC NJM2068V The expression of the unit in this manual is shown by u instead of µ. Please do not make a mistake. Circuit Symbol and No. Part No. Unit Number : CWN3555 Unit Name : Amp Unit A Unit Number : CWN3555 Unit Name : Amp Unit MISCELLANEOUS IC 200 (A,53,49) IC NJM2794RB2 IC 220 (A,51,66) Audio Selector IC NJM2750M IC 230 (A,33,49) IC NJM2794RB2 IC 250 (A,29,66) Audio Selector IC NJM2750M IC 270 (A,14,49) IC NJM2794RB2 IC 700 (A,85,103) IC PAL007C IC 770 (A,156,46) Regulator IC BD9781HFP Q 300 (A,58,87) Transistor UMD2N Q 301 (A,58,80) Transistor UMD2N Q 302 (A,53,87) Transistor DTC323TU Q 303 (A,53,80) Transistor DTC323TU Q 310 (A,58,84) Transistor UMD2N Q 311 (A,58,76) Transistor UMD2N Q 312 (A,53,83) Transistor DTC323TU Q 313 (A,53,76) Transistor DTC323TU Q 710 (A,143,66) Transistor 2SC4081 Q 713 (A,146,66) Chip Transistor DTC114EUA Q 723 (A,145,79) Transistor 2SC4081 Q 725 (A,148,79) Chip Transistor DTC124EUA Q 730 (A,142,96) Transistor 2SC4081 Q 733 (A,132,89) Transistor 2SB1189 Q 740 (A,30,83) Transistor 2SD2318F5 Q 775 (A,164,51) Transistor 2SC4081 Q 776 (A,165,45) Chip Transistor DTA114EUA Q 790 (A,13,61) Transistor 2SA1576A D 200 (A,62,44) Diode DAN217U D 202 (A,62,41) Diode DAN217U D 210 (A,52,40) Diode DAN217U D 212 (A,51,43) Diode DAN217U D 230 (A,41,44) Diode DAN217U D 232 (A,41,41) Diode DAN217U D 240 (A,31,40) Diode DAN217U D 242 (A,30,43) Diode DAN217U D 270 (A,21,22) Diode MALS068X D 280 (A,17,22) Diode MALS068X D 285 (A,14,22) Diode MALS068X D 320 (A,100,85) Diode 1SS355 D 321 (A,100,83) Diode 1SS355 D 700 (A,116,34) Diode ST70-27F D 710 (A,136,64) Diode HZU7R5(B3) D 721 (A,141,76) Diode HZU6R8(B2) D 740 (A,22,87) Diode UDZS8R2(B) D 770 (A,156,33) Diode RB050L-40 D 790 (A,39,13) Diode 1SS355 L 700 (A,121,54) Coil CTH1113 L 720 (A,38,74) Chip Coil BTH1124 L 750 (A,23,78) Chip Coil BTH1124 L 770 (A,139,39) Inductor CTH1253 L 771 (A,148,29) Inductor CTH1253 L 772 (A,159,17) Inductor CTH1381 L 773 (A,157,10) Inductor CTF1718 L 790 (A,42,13) Inductor LCTAW2R2J2520 >FU770 (A,138,20) Fuse 4 A CEK1260 RESISTORS R 200 (A,63,27) RS1/10S103J R 201 (A,61,27) RS1/10S103J R 202 (A,58,27) RS1/10S103J R 203 (A,56,27) RS1/10S103J R 204 (A,57,31) RS1/16S561J R 210 (A,53,27) RS1/10S103J R 211 (A,51,27) RS1/10S103J R 212 (A,48,27) RS1/10S103J R 213 (A,46,27) RS1/10S103J R 214 (A,49,31) RS1/16S561J R 230 (A,42,26) RS1/10S103J R 231 (A,39,26) RS1/10S103J R 232 (A,37,26) RS1/10S103J Circuit Symbol and No. Part No. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com ND-G500/XS/E5 25 5 6 7 8 5 6 7 8 C D F A B E R 233 (A,35,26) RS1/10S103J R 234 (A,36,31) RS1/16S561J R 240 (A,32,26) RS1/10S103J R 241 (A,30,26) RS1/10S103J R 242 (A,28,26) RS1/10S103J R 243 (A,25,26) RS1/10S103J R 244 (A,28,31) RS1/16S561J R 270 (A,21,26) RS1/10S0R0J R 271 (A,18,26) RN1/10SE2202D R 275 (A,13,26) RS1/10S0R0J R 276 (A,16,26) RN1/10SE2202D R 280 (A,19,29) RS1/10S0R0J R 285 (A,15,29) RS1/10S0R0J R 300 (A,48,88) RS1/16S821J R 301 (A,48,81) RS1/16S821J R 302 (A,61,87) RS1/16S104J R 303 (A,72,89) RS1/16S104J R 304 (A,46,87) RS1/16S103J R 305 (A,46,81) RS1/16S103J R 310 (A,48,85) RS1/16S821J R 311 (A,48,78) RS1/16S821J R 312 (A,63,87) RS1/16S104J R 313 (A,74,86) RS1/16S104J R 314 (A,46,84) RS1/16S103J R 315 (A,46,77) RS1/16S103J R 320 (A,96,85) RS1/10S122J R 710 (A,140,63) RS1/10S473J R 711 (A,140,65) RS1/10S473J R 712 (A,140,67) RS1/10S103J R 714 (A,146,70) RS1/10S0R0J R 720 (A,103,29) RS1/8S222J R 721 (A,140,73) RS1/10S223J R 722 (A,143,74) RS1/10S223J R 723 (A,140,79) RS1/10S103J R 724 (A,140,81) RS1/10S153J R 725 (A,137,82) RS1/10S103J R 726 (A,140,83) RS1/10S223J R 727 (A,148,84) RS1/10S331J R 728 (A,145,83) RS1/10S821J R 733 (A,133,96) RS1/8S471J R 734 (A,132,94) RS1/10S103J R 735 (A,139,94) RS1/8S471J R 736 (A,140,92) RS1/10S223J R 740 (A,31,100) RS1/4S821J R 741 (A,23,82) RS1/10S1R0J R 742 (A,39,97) RS1/10S0R0J R 761 (A,55,99) RS1/16S103J R 771 (A,156,37) RS1/16S473J R 772 (A,160,36) RS1/16S473J R 773 (A,163,38) RS1/16S3602D R 774 (A,160,37) RS1/16S7501D R 775 (A,143,72) RS1/10S223J R 776 (A,163,41) RS1/16S473J R 777 (A,149,19) RS1/4S271J R 778 (A,146,19) RS1/4S271J R 779 (A,143,19) RS1/4S271J R 785 (A,165,36) RS1/16S562J R 790 (A,45,16) RS1/10S103J R 792 (A,11,64) RS1/10S472J R 793 (A,10,61) RS1/10S472J Circuit Symbol and No. Part No. R 841 (A,14,64) RS1/16S473J R 842 (A,16,61) RS1/16S103J CAPACITORS C 200 (A,61,33) CEVWNP1R0M50 C 202 (A,57,40) CEVWNP1R0M50 C 210 (A,53,33) CEVWNP1R0M50 C 212 (A,47,37) CEVWNP1R0M50 C 215 (A,58,49) CEHVW100M16 C 220 (A,56,56) CEVWNP1R0M50 C 221 (A,46,56) CEVWNP1R0M50 C 222 (A,61,56) CEVWNP1R0M50 C 223 (A,51,56) CEVWNP1R0M50 C 225 (A,51,61) CKSRYB104K16 C 226 (A,57,64) CKSRYB104K16 C 227 (A,57,69) CKSRYB104K16 C 228 (A,51,72) CKSRYB104K16 C 229 (A,62,65) CEHVW470M16 C 230 (A,40,33) CEVWNP1R0M50 C 232 (A,36,40) CEVWNP1R0M50 C 240 (A,32,33) CEVWNP1R0M50 C 242 (A,26,37) CEVWNP1R0M50 C 245 (A,37,49) CEHVW100M16 C 250 (A,34,56) CEVWNP1R0M50 C 251 (A,25,56) CEVWNP1R0M50 C 252 (A,39,56) CEVWNP1R0M50 C 253 (A,30,56) CEVWNP1R0M50 C 254 (A,29,61) CKSRYB104K16 C 255 (A,35,64) CKSRYB104K16 C 256 (A,35,69) CKSRYB104K16 C 257 (A,28,72) CKSRYB104K16 C 258 (A,39,64) CEHVW470M16 C 270 (A,20,34) CEVWNP100M16 C 271 (A,18,41) CEVWNP100M16 C 275 (A,11,41) CEVWNP100M16 C 276 (A,14,34) CEVWNP100M16 C 277 (A,18,49) CEHVW100M16 C 280 (A,61,91) CKSQYB474K16 C 281 (A,60,94) CKSRYB474K16 C 283 (A,75,89) CKSQYB474K16 C 284 (A,79,89) CKSRYB474K16 C 285 (A,63,91) CKSQYB474K16 C 286 (A,63,94) CKSRYB474K16 C 287 (A,77,86) CKSQYB474K16 C 288 (A,81,86) CKSRYB474K16 C 300 (A,43,88) 10 uF CCG1182 C 301 (A,43,81) 10 uF CCG1182 C 310 (A,43,84) 10 uF CCG1182 C 311 (A,43,79) 10 uF CCG1182 C 320 (A,93,86) 10 uF CCG1182 C 700 (A,121,19) 3 300 uF/16 V CCH1583 C 701 (A,127,39) CKSQYB104K50 C 702 (A,74,22) CCSQCH102J50 C 705 (A,102,103) CKSQYB104K50 C 706 (A,119,88) 3 300 uF/16 V CCH1583 C 725 (A,154,86) CEHVW330M16 C 740 (A,27,93) CEHVW101M16 C 741 (A,22,86) CKSRYB103K50 C 742 (A,17,80) CEHVW331M16 Circuit Symbol and No. Part No. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com ND-G500/XS/E5 26 1 2 3 4 1 2 3 4 C D F A B E C 746 (A,51,49) CKSRYB104K16 C 747 (A,47,49) CEHVW220M16 C 749 (A,30,49) CKSRYB104K16 C 750 (A,26,48) CEHVW220M16 C 751 (A,49,73) CCSRCH101J50 C 752 (A,49,72) CKSRYB224K16 C 753 (A,43,72) CEHVW220M16 C 754 (A,26,73) CCSRCH101J50 C 755 (A,26,72) CKSRYB224K16 C 756 (A,20,72) CEHVW220M16 C 759 (A,12,49) CKSRYB104K16 C 760 (A,8,49) CEHVW220M16 C 761 (A,43,93) CEHVW1R0M50 C 762 (A,53,93) CEHVW101M16 C 763 (A,101,89) CKSQYB225K16 C 764 (A,101,91) 2.2 uF CCG1179 C 771 (A,143,55) CEHVW331M25 C 772 (A,147,42) 10 uF CCG1223 C 773 (A,155,36) CCSRCH101J50 C 774 (A,156,27) 220 uF/10 V CCH1409 C 775 (A,160,25) CKSRYB104K16 C 776 (A,156,39) CKSRYB104K16 C 777 (A,162,38) CKSRYB682K50 C 779 (A,148,11) CEHVW101M16 C 780 (A,154,10) CKSRYB104K16 C 785 (A,164,34) CKSRYB222K50 C 790 (A,44,13) CKSRYB104K16 C 842 (A,17,64) CKSYB105K16 Circuit Symbol and No. Part No. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com
