PIONEER ELECTRONIC CORPORATION 4-1, Meguro 1-Chome, Meguro-ku, Tokyo 153-8654, Japan PIONEER ELECTRONICS SERVICE INC. P.O.Box 1760, Long Beach, CA 90801-1760 U.S.A. PIONEER ELECTRONIC [EUROPE] N.V. Haven 1087 Keetberglaan 1, 9120 Melsele, Belgium PIONEER ELECTRONICS ASIACENTRE PTE.LTD. 501 Orchard Road, #10-00, Wheelock Place, Singapore 238880 C PIONEER ELECTRONIC CORPORATION 1998 K-ZZD. OCT. 1998 Printed in Japan ORDER NO. CRT2287 MULTI-CD/MD CONTROL HIGH POWER MINIDISC PLAYER WITH RDS TUNER MEH-P5000R�EW Service Manual NOTE: - See the separate manual CX-893(CRT2291) for the MD mechanism circuit description and disassembly. - This service manual does not describe the CD test mode. For the operations in the CD test mode, refer to the CD player's Service Manual. - US and foreign patents licensed from Dolby Laboratories Licensing Corporation. CONTENTS 1. SAFETY INFORMATION............................................2 2. EXPLODED VIEWS AND PARTS LIST ......................3 3. SCHEMATIC DIAGRAM...........................................10 4. PCB CONNECTION DIAGRAM................................28 5. ELECTRICAL PARTS LIST........................................40 6. ADJUSTMENT.........................................................48 7. GENERAL INFORMATION.......................................73 7.1PARTS .................................................................73 7.1.1 IC...............................................................73 7.1.2 DISPLAY ...................................................84 7.2DIAGNOSIS ........................................................85 7.2.1 DISASSEMBLY.........................................85 7.3EXPLANATION ...................................................86 7.3.1 BLOCK DIAGRAM....................................86 8. OPERATIONS AND SPECIFICATIONS....................88 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 2 MEH-P5000R 1. SAFETY INFORMATION This service manual is intended for qualified service technicians; it is not meant for the casual do-it-yourselfer. Qualified technicians have the necessary test equipment and tools, and have been trained to properly and safely repair complex products such as those covered by this manual. Improperly performed repairs can adversely affect the safety and reliability of the product and may void the warranty. If you are not qualified to perform the repair of this product properly and safely; you should not risk trying to do so and refer the repair to a qualified service technician. 1. Safety Precautions for those who Service this Unit. • When checking or adjusting the emitting power of the laser diode exercise caution in order to get safe, reliable results. Caution: 1. During repair or tests, minimum distance of 13cm from the focus lens must be kept. 2. During repair or tests, do not view laser beam for 10 seconds or longer. 2. A “CLASS 1 LASER PRODUCT” label is affixed to the bottom of the player. 3. The triangular label is attached to the mechanism module frame. 4. Specifications of Laser Diode Specifications of laser radiation fields to which human access is possible during service. Wavelength = 780 nanometers CLASS 1 LASER PRODUCT Triangular Label www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 3 MEH-P5000R 2. EXPLODED VIEWS AND PARTS LIST 2.1 PACKING 1 Cord Assy CDE5722 2 Accessory Assy CEA1917 3 Screw CBA1284 4 Handle CNC5395 5 Bush CNV1009 * 6 Polyethylene Bag E36-615 7 Polyethylene Bag CEG-162 8 Polyethylene Bag CEG1116 9 Carton CHG3540 10 Contain Box CHL3540 11 Protector CHP2098 12 Protector CHP2099 13 Owner’s Manual CRD2736 14 Owner’s Manual CRD2737 15 Owner’s Manual CRD2738 16 Installation Manual CRD2739 * 17 Label CRW1343 18 Passport CRY1013 * 19 Warranty Card CRY1087 20 Case Assy CXB1063 NOTE: - Parts marked by “*” are generally unavailable because they are not in our Master Spare Parts List. - Screws adjacent to Ñ mark on the product are used for disassembly. - PACKING SECTION PARTS LIST Mark No. Description Part No. Mark No. Description Part No. - Owner's Manual, Installation Manual Model Part No. Language MEH-P5000R/EW CRD2736 English, Spanish CRD2737 German, French CRD2738 Italian, Dutch CRD2739 English, Spanish, German, French, Italian, Dutch www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 4 MEH-P5000R 2.2 EXTERIOR www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 5 MEH-P5000R 1 Screw BSZ26P050FMC 2 Screw BSZ30P060FMC 3 Screw BSZ30P200FMC 4 Connector CDE5718 5 Cord Assy CDE5722 6 Fuse(10A) CEK1136 7 Terminal Cover CKX-003 8 Cord Assy CDE5804 9 Holder CNC5704 10 Holder CNC6798 11 Cushion CNM4870 12 Insulator CNM5752 13 Insulator CNM5921 14 Cushion CNM5925 15 Panel CNS5097 16 Tuner Amp Unit CWM6036 17 Screw BPZ26P080FMC 18 Screw BSZ26P100FMC 19 Screw BSZ26P160FMC 20 Clamper CEF1005 21 Pin Jack(CN452) CKB1028 22 Terminal(CN303) CKF1059 23 Terminal(CN351) CKF1059 24 Plug(CN501) CKM1231 * 25 Connector(CN201) CKS2221 26 Connector(CN751) CKS3408 27 Connector(CN801) CKS3581 28 Connector(CN451) CKS3599 29 Antenna Jack(CN302) CKX1056 30 Holder CNC4569 31 Holder CNC6361 32 Heat Sink CNC7369 33 Holder CNC7370 34 Holder CNC7968 35 Holder CNC8021 36 Insulator CNM4684 37 Heat Sink CNR1419 38 FM/AM Tuner Unit CWE1416 39 Holder CNC6555 40 MD Mechanism Module CXB2784 41 Button CAC5180 42 Door CAT1983 43 Spring CBH1834 44 Spring CBH1835 45 Spring CBH1996 46 Spring CBH2191 47 Bracket CNC6135 48 Bracket CNC6791 49 Panel CNS5096 50 Arm CNV4692 51 Arm CNV4693 52 Arm CNV4951 53 Screw IMS20P030FZK 54 Detach Grille Assy CXB2913 55 Screw BPZ20P080FMC 56 Screw BPZ20P080FZK 57 Button(EJECT) CAC5768 58 Button(SOURCE) CAC5769 59 Button(BAND) CAC5770 60 Button(1-6) CAC5771 61 Button CAC5772 62 Button(D.RESET) CAC5773 63 Button(EQ) CAC5774 64 Spring CBH2190 65 Cover CNS5094 66 Lighting Conductor CNV5505 67 Lighting Conductor CNV5506 68 Holder CNV5511 69 Keyboard Unit CWM6041 70 LCD CAW1490 71 Connector(CN901) CKS3580 72 Holder CNC7969 73 Sheet CNM5923 74 Sheet CNM5924 75 Connector CNV5504 76 Lighting Conductor CNV5507 77 Housing CNV5508 78 Grille Unit CXB2975 79 Case Unit CXB2918 80 IC(IC501) TDA7386 81 Transistor(Q201,952) 2SD2396 82 Chassis Unit CXB2971 83 LED(D903,904,907,908) NSPWF50SB 84 Screw ISS26P055FUC - EXTERIOR SECTION PARTS LIST Mark No. Description Part No. Mark No. Description Part No. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 6 MEH-P5000R 2.3 MD MECHANISM MODULE(1) www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 7 MEH-P5000R 1-100 ••••• 101 Side Plate Assy, Right 1242000280 102 Side Bracket 1242000188 103 Loading Motor Bracket 1242000189 104 Front Guide 1242000190 105 Loading Chassis Assy 1242070066 106 Disc Holder Assy 1242140176 107 Disc Holder Arm 1242400018 108 Mode Gear 1242410003 109 FLT Lock Arm 1242480151 110 FLT Lock Plate 1242480112 111 Clamper Arm 1242480114 112 Loading Plate 1242480105 113 Mode Plate 1242480107 114 Catch Block 1242480108 115 Lift Arm 1242500001 116 Spring, Damper 1242580146 117 Spring, FLT Lock 1242580147 118 Spring, Disk Holder 1242580148 119 Spring, Clamper Arm 1242580149 120 Spring, Lift Arm 1242580150 121 Gear, Worm Wheel 1242810060 122 Gear, Pinion 1242810061 123 Roller, Clamper Arm 1242870012 124 Shaft, Worm Wheel 1242900093 125 Oil Damper 1243300001 126 Spring, FLT Lock Arm 1242580204 127 Spring, Slider 1242580201 128 Spring, Mode Plate 1242580202 129 Spring, Holder Hold 1242580203 130-600 ••••• 601 Screw, 1.7X1.6MM 1249700045 602 Screw, 1.7X2.5MM 1249700040 603 Screw, 2.0X3.0MM 1249700133 604 Screw, 2.0X3.5MM 1249700134 605 Screw, 2.0X2.2MM 1249700135 606 Washer, 1.2X3X0.2MM 1249900021 607 Screw, 2.0X4.0MM 1249700140 608 Washer YE15FUC 609 Screw, 2.0X2.5MM 1249700158 610 Ball CNR1189 611 Loading Motor Assy 1246300043 612 Flat Cable, 8 Pin 1245120221 613 Main PCB Assy 1246840250 614 Switch PCB Assy 1246840145 - MD MECHANISM MODULE(1) PARTS LIST Mark No. Description Part No. Mark No. Description Part No. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 8 MEH-P5000R 2.4 MD MECHANISM MODULE(2) *One or two washers may be added to the parts for fine tuning of accuracy. When you exchange the parts such as (511: spin motor) or (1: motor spacer), mount it exactly as it was placed before the exchange. 15 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 1 Holder Shaft Plate 1242000279 2 Shaft Guide Holder 1242000064 3 Drive Screw Assy Unit 1242000116 4 Main Chassis Assy 1242070065 5 Shaft Catch Spring 1242580007 6 Clip Spring 1242580067 7 Grip Rack 1242810021 8 Pickup Slide Shaft 1242900127 9 Slide Shaft(S) 1242900011 10 Mechanism Cushion 1243260122 11 Spring Cushion 1243260031 12 Spacer(C) 1244130006 13 Mechanism Flexible PCB 1245210120 14 Optical Pickup Assy 1246170023 15 Mechanism PCB Assy 1246840251 16-500 ••••• 501 Screw, 1.4X2MM 1249700138 502 Screw, 1.4X2.5MM 1249700007 503 Screw, 1.4X2.2MM 1249700011 504 Screw, 1.7X4.3MM 1249700055 505 Screw, 1.4X4.5MM 1249700033 506 Screw, 1.4X2.2MM 1309701315 507 Washer, 1.4X0.5MM 1309900937 508 Washer, 2.8X3.9X0.05MM1249900020 509 Balance Weight 1242480150 510 Sled Motor Assy 1246300014 511 Spin Motor Assy 1246300060 9 MEH-P5000R - MD MECHANISM MODULE(2) PARTS LIST Mark No. Description Part No. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 10 MEH-P5000R A 1 2 3 4 B C D 1 2 3 4 3. SCHEMATIC DIAGRAM 3.1 OVERALL CONNECTION DIAGRAM(GUIDE PAGE) Note: When ordering service parts, be sure to refer to “EXPLODED VIEWS AND PARTS LIST” or “ELECTRICAL PARTS LIST”. A-a A-b A-a A-a A-b A-b A-b A-b A-a A-a Large size SCH diagram Guide page Detailed page ANTENNA JACK RDS DECODER FM(100%) AM(30%) : -17dBs : -26dBs M-CD(1kHz 0dB): +2dBs MD(1kHz 0dB): +2dBs B C D E F A-a A www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com RESET TUNER +B REGULATOR VDD REGULATOR DFS ALARM 5 1 6 2 4 3 5 1 6 2 4 3 5 1 6 2 4 3 ELECTRONIC VOLUME, SOURCE SELECT RR+ RR- FR+ FL+ RL+ FR- FL- RL- BACK UP ILM SYSTEM CONTROL GND ACC SYSTEM CONTROLLER RR+ RR- FR+ FL+ RL+ FR- FL- RL- BACK UP ILM SYSTEM CONTROL GND ACC SYSTEM CONTROL CEK1136 DOOR SWITCH MD:+36dBs MD:+10dBs MD:+10dBs MD M-CD FM AM :+2dBs :+2dBs : -17dBs : -26dBs PEE(DFS):+10dBs PEE(DFS):-11dBs A 11 MEH-P5000R 5 6 7 8 A B C D 5 6 7 8 A A-b www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 12 MEH-P5000R A 1 2 3 4 B C D 1 2 3 4 ANTENNA JACK FM(100%) AM(30%) : -17dBs : -26dBs M-CD(1kHz 0dB): +2dBs B A-a A-a A-b www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 13 MEH-P5000R 5 6 7 8 A B C D 5 6 7 8 SYSTEM CONTROLLER RDS DECODER MD(1kHz 0dB): +2dBs C D E F A-a A-a A-b www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 14 MEH-P5000R A 1 2 3 4 B C D 1 2 3 4 RESET TUNER +B REGULATOR VDD REGULATOR 5 1 6 2 4 3 5 1 6 2 4 3 5 1 6 2 4 3 ELECTRONIC VOLUME, SOURCE SELECT RR+ RR- FR+ FL+ RL+ FR- FL- RL- BACK UP CEK1136 DOOR SWITCH MD:+36dBs MD:+10dBs MD:+10dBs MD M-CD FM AM :+2dBs :+2dBs : -17dBs : -26dBs PEE(DFS):+10dBs PEE(DFS):-11dBs A A-a A-b A-b www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 15 MEH-P5000R 5 6 7 8 A B C D 5 6 7 8 VDD REGULATOR DFS ALARM RR+ RR- FR+ FL+ RL+ FR- FL- RL- BACK UP ILM SYSTEM CONTROL GND ACC LER BACK UP ILM SYSTEM CONTROL GND ACC SYSTEM CONTROL CEK1136 PEE(DFS):+10dBs A-b A-a A-b www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 16 MEH-P5000R A 1 2 3 4 B C D 1 2 3 4 3.2 FM/AM TUNER UNIT B 3 1 2 FM/AM TUNER UN B www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 17 MEH-P5000R 5 6 7 8 A B C D 5 6 7 8B ER UNIT A www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 18 MEH-P5000R A 1 2 3 4 B C D 1 2 3 4 LCD BACKLIGHT DUAL ILLUMINATION SELECTOR 1 5 6 3 4 2 1 5 6 3 4 2 1 5 6 3 4 2 1 5 6 3 4 2 D SOURCE PTY TA A C CN801 3.3 KEYBOARD UNIT C www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com KEY CONTROLLER, LCD DRIVER 5.0V 3.4V 1.7V 5.0V 3.4V 1.7V 19 MEH-P5000R 5 6 7 8 A B C D 5 6 7 8C www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 20 MEH-P5000R A 1 2 3 4 B C D 1 2 3 4 D E F D-a 3.4 MD MECHANISM MODULE A-a A-b A-a A-a A-b A-b A-b A-b A-a A-a Large size SCH diagram Guide page Detailed page MAIN PCB MECHANISM PCB OPTICAL PICKUP ASSY SWITCH PCB www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 21 MEH-P5000R 5 6 7 8 A B C D 5 6 7 8 Audio(L ch) Focus Error Tracking Error Sled(Carriage) Spindle D D-b www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 22 MEH-P5000R A 1 2 3 4 B C D 1 2 3 4 D-a D-b D-a MAIN PCB www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 23 MEH-P5000R 5 6 7 8 A B C D 5 6 7 8 D-a D-b D-a E F MECHANISM PCB OPTICAL PICKUP ASSY SWITCH PCB www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 24 MEH-P5000R A 1 2 3 4 B C D 1 2 3 4 Audio(L ch) Focus Error Tracking Error Sled(Carriage) Spindle D-a D-b D-b www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 25 MEH-P5000R 5 6 7 8 A B C D 5 6 7 8 D-a D-b D-b www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 26 MEH-P5000R - Waveforms 1 CH1 : FEMON 5V/div 2ms/div 1 CH2 : FEMON+LPF 2V/div 2ms/div 2 CH3 : TEMON 5V/div 2ms/div 2 CH4 : TEMON+LPF 2V/div 2ms/div Normal mode : play Disc : Recordable Note: The encircled numbers denote measuring pointes in the circuit diagram. 2 CH1 : TEMON+LPF 1V/div 1ms/div 3 CH2 : E 500mV/div 1ms/div 4 CH3 : F 500mV/div 1ms/div Normal mode : play Disc : Recordable 1 CH1 : FEMON 1V/div 2ms/div 1 CH2 : FEMON+LPF 500mV/div 2ms/div 2 CH3 : TEMON 500mV/div 2ms/div 2 CH4 : TEMON+LPF 500mV/div 2ms/div Normal mode : play Disc : Premastered 2 CH1 : TEMON+LPF 1V/div 1ms/div 3 CH2 : E 500mV/div 1ms/div 4 CH3 : F 500mV/div 1ms/div Normal mode : play Disc : Premastered 5 CH1 : EFM 1V/div 500ns/div Test mode : play Disc : Recordable 5 CH1 : EFM 1V/div 500ns/div Test mode : play Disc : Premastered 6 CH1 : WBO 2V/div 100ms/div 7 CH2 : ADLPFO 1V/div 100ms/div Test mode : play Disc : Recordable 8 CH1 : DFCK 5V/div 2ms/div 9 CH2 : BCLK 5V/div 2ms/div 0 CH3 : DADATA 5V/div 2ms/div ! CH3 : LRCK 5V/div 2ms/div Normal mode : play Disc : Recordable 8 CH1 : DFCK 5V/div 200ns/div 9 CH2 : BCLK 5V/div 200ns/div 0 CH3 : DADATA 5V/div 200ns/div ! CH4 : LRCK 5V/div 200ns/div Normal mode : play Disc : Recordable www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 27 MEH-P5000R 1 CH1 : FEMON+LPF 1V/div 100ms/div @ CH2 : F+ 2V/div 100ms/div # CH3 : F- 2V/div 100ms/div @# CH4 : F+ - F- 2V/div 100ms/div Focus close Disc : Recordable @# CH1 : F+ - F- 2V/div 200ms/div 2 CH2 : TEMON+LPF 1V/div 200ms/div $ CH3 : SP+ 2V/div 200ms/div % CH4 : SP- 2V/div 200ms/div Focus close Disc : Recordable 1 CH1 : FEMON+LPF 1V/div 10ms/div ^ CH2 : A 500mV/div 10ms/div & CH3 : B 500mV/div 10ms/div Focus close Disc : Recordable 2 CH1 : TEMON+LPF 1V/div 200ms/div * CH2 : T+ 2V/div 200ms/div ( CH3 : T- 2V/div 200ms/div *( CH4 : T+ - T- 2V/div 200ms/div Test mode : 1T REV jump Disc : Recordable ¤ CH1 : LOADSTART 5V/div 200ms/div ‹ CH2 : LOADEND 5V/div 200ms/div › CH3 : L+ 5V/div 200ms/div fi CH3 : L- 5V/div 200ms/div Loading fl CH1 : EJECTEND 5V/div 200ms/div › CH2 : L+ 5V/div 200ms/div fi CH3 : L- 5V/div 200ms/div Eject 2 CH1 : TEMON+LPF 1V/div 500ms/div * CH2 : T+ 2V/div 500ms/div ( CH3 : T- 2V/div 500ms/div *( CH4 : T+ - T- 2V/div 500ms/div Test mode : 10T REV jump Disc : Recordable 2 CH1 : TEMON+LPF 1V/div 1ms/div ) CH2 : SL+ 2V/div 1ms/div ⁄ CH3 : SL- 2V/div 1ms/div )⁄ CH4 : T+ - T- 2V/div 1ms/div Test mode : 10T REV jump Disc : Recordable 2 CH1 : TEMON+LPF 1V/div 20ms/div ) CH2 : SL+ 2V/div 20ms/div ⁄ CH3 : SL- 2V/div 20ms/div )⁄ CH4 : T+ - T- 2V/div 20ms/div Test mode : 400T REV jump Disc : Recordable www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 28 MEH-P5000R A 1 2 3 4 B C D 1 2 3 4 A A CORD ASSY TUNER AMP UNIT 4. PCB CONNECTION DIAGRAM 4.1 TUNER AMP UNIT NOTE FOR PCB DIAGRAMS 1. The parts mounted on this PCB include all necessary parts for several destination. For further information for respective destinations, be sure to check with the schematic diagram. 2. Viewpoint of PCB diagrams Capacitor Connector P.C.Board Chip Part SIDE A SIDE B www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 29 MEH-P5000R 5 6 7 8 A B C D 5 6 7 8A REAR PREOUT ANTENNA JACK R ch L ch RESET IP BUS IN CN901 C SIDE A FRONT PREOUT CN301 D B www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 30 MEH-P5000R A 1 2 3 4 B C D 1 2 3 4 A A TUNER AMP UNIT www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 31 MEH-P5000R 5 6 7 8 A B C D 5 6 7 8A SIDE B www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 32 MEH-P5000R A 1 2 3 4 B C D 1 2 3 4 4.2 FM/AM TUNER UNIT B SIDE A B A FM/AM TUNER UNIT www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 33 MEH-P5000R 5 6 7 8 A B C D 5 6 7 8 B SIDE B B FM/AM TUNER UNIT www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 5 4 3 1 6 5 4 2 3 1 6 5 4 2 3 1 6 5 4 2 3 1 6 5 4 2 3 1 6 5 4 2 3 1 6 5 4 2 3 1 6 5 4 2 3 1 6 5 4 2 3 1 TA MEH-P5000R A 1 2 3 4 B C D 1 2 3 4 4.3 KEYBOARD UNIT C C KEYBOARD UNIT 34 KEYBOARD UNIT C www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 35 MEH-P5000R 5 6 7 8 A B C D 5 6 7 8C 6 5 4 2 3 1 6 5 4 2 3 1 6 5 4 2 3 1 6 5 4 2 3 1 6 5 4 2 3 1 6 5 4 2 3 1 6 5 4 2 3 1 6 5 4 2 3 1 6 5 4 2 3 1 6 5 4 2 3 1 6 5 4 2 3 1 6 5 4 2 3 1 6 5 4 2 3 1 6 5 4 2 3 1 SIDE A SIDE B CN801 A www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 36 MEH-P5000R A 1 2 3 4 B C D 1 2 3 4 D MAIN PCB D IC,Q Q821 Q801 IC801 Q841 IC861 IC202 IC201 IC401 IC402 IC111 Q402 Q401 Q403 CN201 A CN652 F E 4.4 MAIN PCB SIDE A www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 37 MEH-P5000R 5 6 7 8 A B C D 5 6 7 8D IC,Q IC651 IC811 IC302 IC306 Q822 Q842 IC303 IC301 IC305 IC102 IC101 IC601 IC403 OPTICAL PICKUP ASSY D MAIN PCB SIDE B www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 38 MEH-P5000R A 1 2 3 4 B C D 1 2 3 4 E E MECHANISM PCB MECHANISM PCB E D CN601 4.5 MECHANISM PCB SIDE A SIDE B www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 39 MEH-P5000R 5 6 7 8 A B C D 5 6 7 8F F SWITCH PCB D CN651 4.6 SWITCH PCB SIDE A www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 40 MEH-P5000R 5. ELECTRICAL PARTS LIST NOTE: - Parts whose parts numbers are omitted are subject to being not supplied. - The part numbers shown below indicate chip components. Chip Resistor RS1/_S___J,RS1/__S___J Chip Capacitor (except for CQS.....) CKS....., CCS....., CSZS..... R 8 RS1/16S332J R 9 RS1/16S473J R 10 RS1/16S223J R 11 RS1/16S124J R 13 RS1/16S563J R 15 RS1/16S271J R 16 RS1/16S104J R 17 RS1/16S332J R 18 RS1/16S332J R 31 RS1/16S470J R 32 RS1/16S822J R 33 RS1/16S822J R 34 RS1/16S331J R 35 RS1/16S331J R 51 RS1/16S271J R 52 RS1/16S560J R 55 RS1/16S102J R 56 RS1/16S823J R 61 RS1/16S392J R 62 RS1/16S393J R 101 RS1/16S272J R 102 RS1/16S682J R 103 RS1/16S333J R 104 RS1/16S334J R 105 RS1/16S683J R 107 RS1/16S222J R 151 RS1/16S222J R 152 RS1/16S393J R 154 RS1/16S104J R 155 RS1/16S273J R 156 RS1/16S243J R 157 RS1/16S203J R 160 RS1/16S222J R 161 RS1/16S563J R 162 RS1/16S105J R 163 RS1/16S222J R 202 RS1/16S223J R 203 RS1/16S225J R 204 RS1/16S103J R 206 RS1/16S220J R 207 RS1/16S101J R 208 RS1/16S102J R 209 RS1/16S471J R 214 RS1/16S822J R 215 RS1/16S822J R 217 RS1/16S102J R 231 RS1/16S272J R 232 RS1/16S473J R 237 RS1/16S103J R 238 RS1/16S104J R 239 RS1/16S104J R 240 RS1/16S332J R 241 RS1/16S202J R 243 RS1/16S123J R 244 RS1/16S103J Unit Number : CWE1416 Unit Name : FM/AM Tuner Unit MISCELLANEOUS IC 1 IC PA4023B IC 2 IC PA4024A Q 1 Transistor 2SC2412K Q 2 Transistor DTC124EU Q 3 FET 3SK263 Q 31 Transistor 2SC2412K Q 154 Transistor DTC124EU Q 165 Transistor 2SC2412K Q 201 FET 2SK932 Q 202 Transistor 2SC2412K Q 203 Transistor DTC124EU D 4 Diode 1SV250 D 5 Diode KV1410-F1 D 7 Diode KV1410-F1 D 8 Diode KV1410-F1 D 201 Diode MA157 D 202 Diode MA157 D 231 Diode SVC253 L 2 Coil CTC1108 L 3 Inductor LCTB2R2K2125 L 4 Coil CTC1108 L 5 Coil CTC1107 L 6 Inductor LCTBR15K1608 L 51 Ferri-Inductor LAU150K L 201 Ferri-Inductor LAU4R7K L 202 Ferri-Inductor LAU330K L 203 Inductor CTF1287 L 208 Inductor LAU121K L 231 Inductor LCTA3R3J3225 T 31 Coil CTE1116 T 51 Coil CTC1136 TC 1 CCL1046 CF 51 Ceramic Filter CTF1442 CF 52 Ceramic Filter CTF1442 CF 53 Ceramic Filter CTF1442 CF 232 Ceramic Filter CTF1348 X 151 Resonator 918.5Hz CSS1365 X 231 Crystal Resonator 10.26MHz CSS1111 VR 154 Semi-fixed 150k½(B) CCP1213 AR 1 DSP-201M RESISTORS R 1 RS1/16S0R0J R 4 RS1/16S154J R 5 RS1/16S391J R 6 RS1/16S223J R 7 RS1/16S123J =====Circuit Symbol & No.===Part Name Part No. --- ------ ------------------------------------------ ------------------------- =====Circuit Symbol & No.===Part Name Part No. --- ------ ------------------------------------------ ------------------------- B www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 41 MEH-P5000R R 247 RS1/16S123J CAPACITORS C 1 CCSQCH6R0D50 C 2 CCSRCK2R0C50 C 4 CCSRCH820J50 C 6 CCSRCH820J50 C 8 CKSRYB103K25 C 9 CKSQYB104K16 C 10 CCSRCKR50C50 C 11 CEJA1R0M50 C 13 CKSRYB222K50 C 14 CCSRCH220J50 C 16 CCSRCH8R0D50 C 17 CKSRYB222K50 C 18 CKSRYB103K25 C 19 CKSRYB222K50 C 20 CKSRYB222K50 C 21 CEJA100M16 C 22 CCSRTH9R0D50 C 23 CCSRTH120J50 C 24 CCSRCH471J50 C 25 CKSRYB103K25 C 31 CKSRYB103K25 C 32 CKSQYB472K50 C 33 CCSRCH5R0C50 C 34 CKSQYB104K16 C 36 CCSRRH201J50 C 51 CKSRYB223K25 C 52 CKSRYB103K25 C 54 CCSRCH470J50 C 55 CKSQYB223K25 C 56 CKSQYB104K16 C 57 CKSRYB472K50 C 58 CEJA330M10 C 59 CKSRYB103K25 C 61 CCSRCH270J50 C 62 CKSRYB103K25 C 63 CEJAR15M50 C 101 CEJANP100M10 C 102 CKSRYB182K50 C 103 CKSRYB682K25 C 104 CEJA2R2M50 C 105 CKSRYB103K25 C 106 CCSRCH151J50 C 107 CKSRYB103K25 C 151 CKSRYB472K50 C 152 CKSQYB104K16 C 153 CEJA3R3M50 C 154 CKSQYB104K16 C 157 CEJA3R3M50 C 158 CKSYB474K16 C 159 CEJA220M6R3 C 160 CKSQYB104K16 C 161 CKSQYB104K16 C 162 CEJA3R3M50 C 163 CKSRYB102K50 C 170 CCSRCH100D50 C 201 CCSRCH471J50 C 202 CCSRCH100D50 C 203 CKSRYB332K50 C 204 CKSQYB473K16 C 205 CKSQYB473K16 C 206 CKSQYB104K16 C 207 CCSRCH560J50 C 209 CKSQYB104K16 C 211 CCSRCH101J50 C 212 CEJA470M6R3 C 213 CKSRYB103K25 C 216 CCSRCH101J50 C 217 CEJA1R5M50 C 219 CCSRCH471J50 C 220 CKSRYB103K25 C 230 CKSRYB103K25 C 231 CCSRCH330J50 C 232 CCSRCH150J50 C 233 CKSQYB104K16 C 234 CEJA330M10 C 235 CKSRYB332K50 C 236 CKSQYB473K16 C 237 CCSRCH120J50 C 239 CKSRYB472K50 C 240 CEJAR47M50 C 241 CKSQYB104K16 C 242 CEJAR47M50 C 243 CEJAR33M50 C 244 CKSQYB473K16 C 245 CKSRYB123K25 C 246 CKSQYB473K16 C 250 CCSRCH471J50 Unit Number : Unit Name : Main PCB MISCELLANEOUS IC 101 IC 1245730345 IC 102 IC IR3C14 IC 201 IC 1245730449 IC 202 IC 1245730308 IC 301 IC 1245730310 IC 302 IC 1245730313 IC 303 IC 1245730310 IC 305 IC 1245730086 IC 306 IC 1245730086 IC 401 IC 1245730445 IC 402 IC 1245730376 IC 403 IC 1245730309 IC 501 IC 1245730441 IC 601 IC 1245730184 IC 651 IC 1245730443 IC 801 IC 1245730444 IC 811 IC 1105730631 IC 861 IC 1245730311 Q 402 1245760006 Q 403 DTA114TE Q 703 Transistor 2SA1037K Q 704 DTC114EE Q 705 Transistor 2SC4213 Q 706 Transistor 2SC4213 Q 801 Transistor 1245760001 Q 802 FET 2SK1830 Q 821 Transistor 2SA1244LB Q 822 Transistor 2SC4081 Q 841 Transistor 2SA1244LB Q 842 Transistor 2SC4081 D 701 Diode 1115700031 L 101 Inductor 1246140017 L 201 Inductor 1246140016 L 202 Inductor 1246140016 L 501 Inductor 1246140016 L 600 Inductor 1246120002 L 601 Inductor 1306140314 L 602 Inductor 1306140314 L 603 Inductor 1246120002 L 604 Inductor 1246120002 =====Circuit Symbol & No.===Part Name Part No. --- ------ ------------------------------------------ ------------------------- =====Circuit Symbol & No.===Part Name Part No. --- ------ ------------------------------------------ ------------------------- D www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 42 MEH-P5000R L 605 Inductor 1306140314 L 606 Inductor 1306140314 L 607 Inductor 1306140314 L 608 Inductor 1306140314 L 612 Inductor 1246140014 L 651 Inductor 1246140014 L 801 Inductor 1246140014 L 802 Inductor 1306140314 L 842 Inductor 1246120002 J 801 RS1/8S0R0J J 803 RS1/8S0R0J XL 401 Ceramic Resonator 1245790006 B 701 RS1/16SS0R0J XL 201 Crystal Resonator 1246160020 B 702 RS1/16SS0R0J J 301 RS1/16SS0R0J RESISTORS R 101 RS1/16SS823J R 102 RS1/16SS563J R 103 RS1/16SS104J R 104 RS1/16SS104J R 105 RS1/16SS104J R 111 RS1/16SS223J R 112 RS1/16SS223J R 113 RS1/16SS223J R 114 RS1/16SS223J R 121 RS1/16SS0R0J R 122 RS1/16SS0R0J R 123 RS1/16SS0R0J R 124 RS1/16SS0R0J R 131 RS1/16SS1R0J R 143 RS1/16SS0R0J R 144 RS1/16SS0R0J R 145 RS1/16SS0R0J R 146 RS1/16SS0R0J R 161 RS1/16SS122J R 204 RS1/16SS102J R 222 RS1/16SS105J R 223 RS1/16SS0R0J R 303 RS1/16SS103J R 304 RS1/16SS332J R 305 RS1/16SS473J R 306 RS1/16SS681J R 307 RS1/16SS681J R 308 RS1/16SS681J R 309 RS1/16SS681J R 310 RS1/16SS681J R 311 RS1/16SS102J R 312 RS1/16SS102J R 314 RS1/16SS0R0J R 402 RS1/16SS0R0J R 403 RS1/16SS223J R 404 RS1/16SS223J R 405 RS1/16SS0R0J R 406 RS1/16SS223J R 407 RS1/16SS223J R 408 RS1/16SS223J R 409 RS1/16SS223J R 411 RS1/16SS104J R 412 RS1/16SS103J R 413 RS1/16SS102J R 414 RS1/16SS102J R 415 RS1/16SS102J R 431 RS1/16SS104J R 432 RS1/16SS104J R 433 RS1/16SS104J R 441 RS1/16SS102J R 442 RS1/16SS102J R 443 RS1/16SS102J R 444 RS1/16SS102J R 445 RS1/16SS102J R 446 RS1/16SS102J R 448 RS1/16SS103J R 510 RS1/16SS100J R 511 RS1/16SS0R0J R 512 RS1/16SS0R0J R 513 RS1/16SS0R0J R 514 RS1/16SS0R0J R 601 RS1/16SS103J R 709 RS1/16SS681J R 710 RS1/16SS681J R 713 RS1/16SS104J R 714 RS1/16SS104J R 717 RS1/16SS561J R 718 RS1/16SS561J R 719 RS1/16SS102J R 720 RS1/16SS102J R 721 RS1/16SS103J R 722 RS1/16SS103J R 723 RS1/16SS681J R 801 RS1/16SS223J R 802 RS1/16SS471J R 803 1245810051 R 804 1305810059 R 805 1245810088 R 806 1245810090 R 807 RS1/16SS473J R 808 1245810098 R 821 1245810091 R 822 RS1/16SS101J R 823 1245810087 R 824 1245810050 R 826 RS1/16SS0R0J R 828 1245810082 R 841 1245810091 R 842 RS1/16SS101J R 843 1245810087 R 844 1245810050 R 848 1245810082 CAPACITORS C 101 CSZS100M10 C 102 CKSQYB105K16 C 103 CKSQYB105K16 C 104 CKSRYB273K16 C 106 CKSQYB224K16 C 107 CKSRYB123K25 C 109 CKSYB475K10 C 110 CKSQYB224K16 C 111 RS1/10S0R0J C 112 CKSRYB332K50 C 113 CKSRYB333K16 C 114 CCSRCH331J50 C 121 CCSRCH271J50 C 122 CCSRCH271J50 C 123 CCSRCH391J50 C 124 CCSRCH391J50 C 131 CKSRYB123K25 C 132 CKSQYB105K16 C 140 CKSRYB104K16 C 166 CSZS100M10 C 201 1245950015 C 202 CSZS100M10 C 203 CKSRYB104K16 C 204 CKSRYB104K16 C 205 CKSQYB105K16 =====Circuit Symbol & No.===Part Name Part No. --- ------ ------------------------------------------ ------------------------- =====Circuit Symbol & No.===Part Name Part No. --- ------ ------------------------------------------ ------------------------- www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 43 MEH-P5000R C 211 CCSRCH100D50 C 212 CCSRCH100D50 C 301 CKSRYB104K16 C 302 CKSRYB104K16 C 303 CKSRYB104K16 C 305 CKSRYB104K16 C 306 CKSRYB104K16 C 307 CKSQYB224K16 C 401 CKSQYB105K16 C 402 CKSYB105K16 C 403 CKSQYB105K16 C 405 CKSRYB104K16 C 501 1245900059 C 502 CKSYB105K16 C 511 CSZS100M10 C 512 CKSQYB104K16 C 513 CSZS100M10 C 514 CKSQYB104K16 C 515 CSZS100M10 C 516 CKSQYB104K16 C 517 CKSRYB104K16 C 518 CKSRYB104K16 C 600 1245950015 C 601 CKSQYB105K16 C 602 CKSQYB105K16 C 603 CKSQYB105K16 C 604 CKSQYB105K16 C 605 CKSQYB105K16 C 606 CKSQYB105K16 C 607 CKSQYB105K16 C 608 CKSQYB105K16 C 611 CKSYB105K16 C 612 CKSRYB104K16 C 613 CKSYB225K16 C 651 CKSYB105K16 C 652 CKSRYB104K16 C 705 1245920014 C 706 1245920014 C 707 CCSRCH151J50 C 708 CCSRCH151J50 C 801 CKSYB105K16 C 802 CKSRYB104K16 C 803 CKSYB105K16 C 804 1245900058 C 805 CKSYB105K16 C 806 1245900059 C 807 CKSYB105K16 C 808 CKSQYB184K16 C 809 1245900058 C 810 CKSYB103K25 C 821 CCSRSL681J50 C 824 1245900003 C 825 1245900059 C 826 1245900059 C 827 CCSRCH151J50 C 840 CKSYB105K16 C 841 CKSRYB222K50 C 842 CCSRCH151J50 C 843 CKSQYB224K16 C 844 1245900059 C 846 1245900059 C 847 1245900059 C 861 CKSYB105K16 C 862 1245900058 Unit Number : CWM6036 Unit Name : Tuner Amp Unit MISCELLANEOUS IC 301 IC PM2007A IC 351 IC PMW001B IC 352 IC TA75S393F IC 401 IC PML003AM IC 501 IC TDA7386 IC 552 IC TPD1018F IC 601 IC PD4960A IC 602 IC S-80734ANDYI IC 751 IC CA0008AM Q 201 Transistor 2SD2396 Q 202 Transistor DTA114EK Q 203 Transistor DTC124EK Q 251 Transistor 2SA1037K Q 252 Transistor DTC124EK Q 253 Transistor 2SC2412K Q 301 Transistor 2SC2412K Q 302 Transistor IMD2A Q 351 Transistor 2SC2412K Q 451 Transistor IMH3A Q 452 Transistor IMH3A Q 453 Transistor DTA124EK Q 455 Transistor DTC124EK Q 456 Transistor 2SC2412K Q 457 Transistor DTC124EK Q 551 Transistor 2SC2412K Q 552 Transistor 2SC2412K Q 553 Transistor 2SC2412K Q 554 Transistor 2SA1037K Q 601 Transistor DTC124EK Q 602 Transistor DTA114EK Q 701 Transistor 2SD1757K Q 702 Transistor 2SD1757K Q 703 Transistor DTC143TK Q 704 Transistor DTC143TK Q 705 Transistor 2SC2412K Q 706 Transistor DTA114EK Q 751 Transistor 2SA1037K Q 752 Transistor DTC114EK Q 801 Transistor 2SA1037K Q 802 Transistor 2SB1243 Q 803 Transistor DTC143EK Q 804 Transistor 2SA1037K Q 805 Transistor DTC114EK Q 807 Transistor DTC124EK Q 951 Transistor 2SA1037K Q 952 Transistor DTC114EK Q 953 Transistor 2SD2396 Q 954 Transistor 2SA1048 Q 955 Transistor 2SA1048 Q 956 Transistor IMH1A Q 957 Transistor 2SA1037K Q 958 Transistor DTC124EK Q 959 Transistor 2SD1760F5 D 201 Diode HZS7L(A3) D 251 Diode MA3150(M) D 252 LED BR4361F D 301 Chip Diode MA151K D 302 Chip Diode MA151K D 451 Chip Diode MA151WK D 452 Diode HZS9L(A2) =====Circuit Symbol & No.===Part Name Part No. --- ------ ------------------------------------------ ------------------------- =====Circuit Symbol & No.===Part Name Part No. --- ------ ------------------------------------------ ------------------------- A www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 44 MEH-P5000R D 501 Diode ERA15-02 D 502 Diode ERA15-02 D 551 Diode HZS7L(C2) D 552 Diode MA3062(M) D 553 Diode ERA15-02 D 554 Chip Diode MA151WK D 556 Diode ERA15-02 D 558 Diode ERA15-02 D 601 Diode 1SS270 D 801 Diode MA153 D 802 Diode MA153 D 803 Diode MA153 D 804 Diode MA3062(M) D 951 Diode HZS9L(B3) D 952 Diode ERA15-02 D 953 Diode HZS6L(B2) D 954 Diode 1SS270 L 201 Ferri-Inductor LAU2R2K L 301 Ferri-Inductor LAU2R2K L 303 Ferri-Inductor LAU2R2K L 304 Ferri-Inductor LAU2R2K L 351 Ferri-Inductor LAU101K L 501 Choke Coil 600mH CTH1226 L 551 Ferri-Inductor LAU2R2K L 601 Ferri-Inductor LAU2R2K L 602 Ferri-Inductor LAU2R2K L 603 Ferri-Inductor LAU2R2K L 604 Ferri-Inductor LAU2R2K L 605 Inductor LCTB2R2K2125 L 751 Ferri-Inductor LAU2R2K L 801 Ferri-Inductor LAU2R2K CF 601 Filter CTF1071 X 301 Crystal Resonator 7.200MHz CSS1379 X 351 Crystal Resonator 4.332MHz CSS1056 X 601 Resonator 12.58291MHz CSS1402 S 601 Switch(Reset) CSG1046 VR 351 Semi-fixed 22kΩ(B) CCP1321 FM/AM Tuner Unit CWE1416 BZ 601 Buzzer CPV1011 RESISTORS R 201 RS1/10S221J R 202 RS1/10S221J R 204 RS1/10S221J R 206 RD1/4PU221J R 207 RD1/4PU162J R 251 RS1/10S103J R 252 RS1/10S102J R 253 RS1/10S223J R 254 RS1/10S223J R 255 RS1/10S103J R 256 RS1/10S751J R 257 RS1/10S473J R 258 RS1/10S272J R 259 RS1/10S223J R 260 RS1/8S102J R 261 RS1/10S221J R 262 RS1/10S221J R 301 RS1/10S272J R 302 RS1/10S272J R 305 RS1/10S0R0J R 306 RS1/10S102J R 307 RS1/10S0R0J R 308 RS1/10S102J R 309 RS1/10S222J R 310 RS1/10S473J R 311 RS1/10S0R0J R 312 RS1/10S222J R 313 RS1/10S472J R 314 RS1/10S682J R 315 RS1/10S682J R 316 RS1/10S472J R 317 RS1/10S561J R 318 RS1/10S103J R 319 RS1/10S222J R 320 RS1/10S152J R 321 RS1/10S392J R 322 RS1/10S392J R 323 RS1/10S272J R 324 RS1/10S103J R 325 RS1/10S393J R 326 RS1/10S222J R 327 RS1/10S681J R 328 RA4C681J R 329 RS1/10S473J R 330 RS1/10S222J R 331 RS1/10S562J R 332 RS1/10S0R0J R 333 RS1/10S102J R 334 RS1/10S222J R 335 RS1/10S473J R 336 RS1/10S562J R 337 RS1/10S105J R 338 RS1/10S222J R 339 RS1/10S102J R 340 RS1/10S102J R 341 RS1/10S0R0J R 351 RS1/10S333J R 352 RA4C102J R 356 RS1/10S102J R 357 RS1/10S102J R 358 RS1/10S102J R 359 RS1/10S222J R 360 RS1/10S222J R 361 RS1/10S562J R 362 RS1/10S473J R 363 RS1/10S473J R 364 RS1/10S684J R 365 RS1/10S681J R 366 RS1/10S562J R 368 RS1/10S103J R 401 RD1/4PU751J R 402 RD1/4PU751J R 405 RD1/4PU181J R 406 RD1/4PU181J R 407 RD1/4PU223J R 408 RD1/4PU223J R 409 RD1/4PU102J R 410 RD1/4PU102J R 411 RS1/10S102J R 412 RS1/10S102J R 413 RS1/10S102J R 451 RD1/4PU821J R 452 RD1/4PU821J R 453 RD1/4PU821J R 454 RD1/4PU821J R 455 RS1/10S223J R 456 RS1/10S223J R 457 RS1/10S223J R 458 RS1/10S223J R 460 RD1/4PU182J =====Circuit Symbol & No.===Part Name Part No. --- ------ ------------------------------------------ ------------------------- =====Circuit Symbol & No.===Part Name Part No. --- ------ ------------------------------------------ ------------------------- www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 45 MEH-P5000R R 461 RS1/10S103J R 462 RS1/10S223J R 463 RS1/10S103J R 464 RS1/10S103J R 501 RS1/10S221J R 502 RS1/10S101J R 503 RS1/10S153J R 504 RS1/10S103J R 551 RS1/10S223J R 552 RS1/10S473J R 553 RS1/10S223J R 554 RS1/10S473J R 555 RS1/10S472J R 556 RS1/10S103J R 557 RS1/10S103J R 558 RS1/10S473J R 559 RD1/4PU153J R 560 RS1/10S472J R 561 RS1/10S472J R 562 RS1/10S102J R 563 RS1/10S473J R 564 RS1/10S473J R 565 RS1/10S103J R 567 RD1/4PU102J R 568 RD1/4PU102J R 569 RS1/10S473J R 570 RS1/10S473J R 571 RS1/10S0R0J R 572 RS1/10S0R0J R 573 RS1/10S0R0J R 574 RS1/10S0R0J R 601 RS1/10S152J R 602 RS1/10S152J R 603 RS1/10S822J R 604 RS1/10S471J R 606 RS1/10S0R0J R 608 RS1/10S473J R 609 RS1/10S102J R 610 RS1/10S473J R 611 RS1/10S473J R 612 RS1/10S0R0J R 613 RS1/10S102J R 614 RS1/10S102J R 615 RS1/10S102J R 617 RS1/10S102J R 618 RS1/10S222J R 619 RS1/10S473J R 620 RS1/10S473J R 621 RS1/10S473J R 622 RS1/10S473J R 623 RS1/10S221J R 624 RS1/10S102J R 625 RA4C221J R 626 RS1/10S473J R 627 RS1/10S473J R 629 RS1/10S0R0J R 701 RS1/10S224J R 702 RS1/10S224J R 703 RS1/10S222J R 704 RS1/10S222J R 705 RS1/10S223J R 706 RS1/10S223J R 707 RS1/10S224J R 751 RS1/10S102J R 752 RS1/10S102J R 753 RS1/10S473J R 754 RS1/10S473J R 755 RS1/10S101J R 756 RS1/10S101J R 757 RS1/10S620J R 758 RS1/10S223J R 759 RS1/10S102J R 760 RS1/10S102J R 761 RS1/10S222J R 762 RS1/10S472J R 801 RS1/10S223J R 802 RS1/10S332J R 803 RS1/10S0R0J R 804 RS1/10S222J R 805 RS1/10S222J R 806 RS1/10S222J R 807 RS1/10S222J R 808 RS1/10S222J R 809 RS1/10S222J R 810 RS1/10S222J R 811 RS1/4S182J R 813 RS1/10S473J R 814 RS1/4S512J R 816 RS1/10S1R0J R 819 RS2PMF330J R 820 RS2PMF180J R 951 RS1/10S473J R 952 RS1/10S472J R 953 RD1/4PU102J R 954 RS1/10S103J R 955 RS1/10S362J R 956 RS1/10S103J R 957 RS1/10S362J R 958 RS1/10S101J R 959 RS1/10S104J R 960 RS1/8S222J R 961 RS1/10S104J R 962 RS1/10S103J R 963 RS1/10S103J R 964 RS1/10S0R0J R 966 RS1/10S0R0J CAPACITORS C 203 CEJA101M10 C 204 CKSQYB473K25 C 205 CKSQYB103K50 C 251 CKSQYB104K50 C 252 CKSQYB103K50 C 301 CKSQYB223K50 C 302 CKSQYB223K50 C 303 CKSYB105K16 C 304 CKSYB105K16 C 307 CKSQYB223K50 C 308 CKSQYB103K50 C 309 CKSQYB273K50 C 310 CKSQYB103K50 C 311 CKLSR473K16 C 312 CKSQYB223K50 C 314 CKSQYB223K50 C 319 CKSQYB103K50 C 320 CEJA220M10 C 321 CKSQYB103K50 C 322 CKSQYB471K50 C 323 CKSQYB103K50 C 325 CKSQYB103K50 C 326 CKSQYB103K50 C 327 CCSQCH101J50 C 328 CCSQCH101J50 =====Circuit Symbol & No.===Part Name Part No. --- ------ ------------------------------------------ ------------------------- =====Circuit Symbol & No.===Part Name Part No. --- ------ ------------------------------------------ ------------------------- www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 46 MEH-P5000R C 329 CEJA220M6R3 C 330 CKSQYB473K25 C 332 CKSQYB103K50 C 335 CEJA220M10 C 336 CKSQYB103K50 C 337 4.7µF/16V CCH1250 C 339 CKSQYB103K50 C 340 CKSQYB103K50 C 341 4.7µF/16V CCH1250 C 342 CCSQCH150J50 C 343 CCSQCH150J50 C 345 CEJAR47M50 C 346 CKSQYB103K50 C 347 CEJA100M16 C 351 CEJA100M16 C 352 CCSQCH101J50 C 353 CKSQYB222K50 C 354 CKSQYB104K50 C 355 CKSYB105K16 C 356 CKSQYB104K50 C 357 CKSQYB472K50 C 358 CEJA4R7M35 C 359 CKSQYB104K50 C 360 CCSQCH220J50 C 361 CCSQCH220J50 C 362 CKSQYB103K50 C 363 CKSQYB104K50 C 364 CKSQYB223K50 C 403 CKSQYB105K10 C 404 CKSQYB105K10 C 405 CKSQYB105K10 C 406 CKSQYB105K10 C 407 CKSQYB105K10 C 408 CKSQYB105K10 C 409 CKSQYB224K16 C 410 CKSQYB224K16 C 411 CKSQYB105K10 C 412 CKSQYB105K10 C 413 CKSQYB153K50 C 414 CKSQYB153K50 C 415 CKSQYB104K50 C 416 CEJA470M10 C 417 CEJA100M16 C 451 CEJA2R2M50 C 452 CEJA2R2M50 C 453 CEJA2R2M50 C 454 CEJA2R2M50 C 455 CCSQCH101J50 C 456 CCSQCH101J50 C 457 CCSQCH101J50 C 458 CCSQCH101J50 C 501 4700µF/16V CCH1187 C 502 CKSQYB104K50 C 503 CKSYB224K16 C 504 CKSYB224K16 C 505 CKSYB224K16 C 506 CKSYB224K16 C 507 CEJA330M10 C 508 CEJA1R0M50 C 509 CKSQYB105K10 C 510 CEJA100M16 C 551 CKSYB105K16 C 556 CKSQYB473K25 C 558 CKSQYB473K25 C 602 CEJA2R2M50 C 603 CCSQCH200J50 C 604 CCSQCH200J50 C 605 CKSQYB104K50 C 606 CCSQCH101J50 C 607 CCSQCH101J50 C 612 CCSQCH101J50 C 701 CKSQYB223K50 C 751 CKSQYB102K50 C 752 CKSQYB102K50 C 753 CKSQYB104K50 C 803 CCSQCH101J50 C 804 CKSQYB104K50 C 805 CCSQCH101J50 C 951 CEJA101M10 C 952 CKSQYB103K50 C 953 CKSQYB473K25 C 954 CEJA101M10 C 955 1500µF/16V CCH1201 C 956 CEJA100M16 C 957 CKSQYB103K50 C 958 CEJA470M10 Unit Number : CWM6041 Unit Name : Keyboard Unit MISCELLANEOUS IC 901 IC PD6277A IC 902 IC LC75874W IC 903 IC RS-140 Q 901 Transistor IMH10A Q 903 Transistor IMH10A Q 904 Transistor IMH10A Q 905 Transistor IMH10A Q 906 Transistor DTC143TK Q 907 Transistor 2SC2412K D 901 Diode MA153 D 902 Diode MA153 D 903 LED NSPWF50SB D 904 LED NSPWF50SB D 907 LED NSPWF50SB D 908 LED NSPWF50SB D 909 LED CL170DCD D 910 LED CL170DCD D 911 LED CL170PGCD D 912 LED CL170PGCD D 913 LED CL170DCD D 914 LED CL170PGCD D 915 LED CL170SBX L 901 Inductor LCTB4R7K3216 X 901 Resonator 5.00MHz CSS1423 S 901 Switch CSG1115 S 902 Switch CSG1113 S 903 Switch CSG1113 S 904 Switch CSG1113 S 905 Switch CSG1113 S 906 Switch CSG1113 S 907 Switch CSG1113 S 908 Switch CSG1043 S 909 Switch CSG1043 S 910 Switch CSG1113 S 911 Switch CSG1113 S 912 Switch CSG1113 S 913 Switch CSG1113 S 914 Switch CSG1113 S 915 Switch CSG1113 S 916 Switch CSG1113 =====Circuit Symbol & No.===Part Name Part No. --- ------ ------------------------------------------ ------------------------- =====Circuit Symbol & No.===Part Name Part No. --- ------ ------------------------------------------ ------------------------- C www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 47 MEH-P5000R S 917 Switch CSG1113 S 918 Switch CSG1113 S 919 Switch CSG1113 S 920 Switch CSG1113 S 921 Switch CSG1113 S 922 Switch CSG1113 S 923 Switch CSG1113 LCD 901 LCD CAW1490 RESISTORS R 901 RS1/10S222J R 902 RS1/10S222J R 903 RS1/10S103J R 904 RS1/10S121J R 905 RS1/10S2R2J R 907 RA4C102J R 908 RS1/16S102J R 909 RS1/16S102J R 910 RA4C102J R 911 RA4C102J R 912 RA4C103J R 913 RS1/8S751J R 915 RS1/8S751J R 916 RS1/16S472J R 917 RS1/16S472J R 918 RS1/16S472J R 919 RS1/16S473J R 920 RA4C102J R 921 RS1/16S472J R 922 RS1/16S472J R 923 RS1/16S472J R 924 RS1/10S472J R 925 RS1/8S751J R 926 RS1/8S751J R 928 RS1/8S751J R 929 RS1/8S181J R 930 RS1/8S181J R 931 RS1/8S121J R 932 RS1/8S121J R 933 RS1/8S121J R 934 RS1/8S121J R 935 RS1/8S121J R 936 RS1/8S121J R 937 RS1/8S121J R 938 RS1/8S121J R 939 RS1/8S121J R 940 RS1/8S121J R 941 RS1/8S181J R 942 RS1/8S181J R 943 RS1/8S121J R 944 RS1/8S121J R 949 RS1/8S242J R 950 RS1/10S103J R 1001 RS1/8S242J R 1002 RS1/8S242J R 1003 RS1/8S242J R 1004 RS1/8S561J R 1005 RS1/8S561J R 1007 RS1/10S0R0J R 1009 RS1/8S561J R 1010 RS1/8S181J R 1011 RS1/8S181J R 1012 RS1/8S751J CAPACITORS C 902 CSZSR100M6R3 C 903 CSZSR100M6R3 C 904 CKSQYB473K16 C 905 CKSQYB104K16 C 906 CKSQYB681K50 C 907 CKSQYB104K16 C 908 CKSQYB104K16 C 909 CKSQYB104K16 C 910 CKSQYB104K16 C 911 CKSQYB104K16 C 913 CKSQYB104K16 C 914 CKSQYB104K16 C 917 CKSQYB104K16 C 918 CKSQYB104K16 C 919 CKSQYB104K16 Unit Number : Unit Name : Mechanism PCB SW 901 Switch CSN1033 SW 902 Switch 1245300030 SW 903 Switch 1245300030 R 901 RS1/16SS104J R 902 RS1/16SS333J R 903 RS1/16SS104J C 901 CKSYB105K16 C 902 CKSYB105K16 Unit Number : Unit Name : Switch PCB SW 651 Switch 1305301313 SW 652 Switch 1305301313 SW 653 Switch 1305301313 C 653 CKSRYB104K16 Miscellaneous Parts List Optical Pickup Assy 1246170023 Sled Motor Assy 1246300014 Loading Motor Assy 1246300043 Spin Motor Assy 1246300060 =====Circuit Symbol & No.===Part Name Part No. --- ------ ------------------------------------------ ------------------------- =====Circuit Symbol & No.===Part Name Part No. --- ------ ------------------------------------------ ------------------------- E F www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 48 MEH-P5000R FM/AM TUNER UNIT 4½ 4½ Lch + Lch - Rch + Rch - BACK UP ACC GND +14.4V GND Antenna Jack mV Meter(1) Oscilloscope DC Regulated Power Supply TUNER AMP UNIT DC V Meter(1) Center Meter Pin 19 FM/AM TUNER UNIT (BOTTOM VIEW) C63 FM/AM TUNER UNIT (TOP VIEW) L2 L5 T51 T31 Pin1 Pin13 Pin14 Pin26 L4 T51 VR154 50 ½(75½ ) FM SSG Stereo Modulator 50½ (37.5½ ) Antenna Plug Dummy Antenna VR351 DC V Meter(2) SIDE B Q351 EMITTER TC1 6. ADJUSTMENT 6.1 TUNER ADJUSTMENT - Connection Diagram www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 49 MEH-P5000R Modulation M:MONO MOD., 400Hz 30%(22.5kHz Dev.) S1:STEREO MOD., 1kHz, L or R=30%(20.25kHz+7.5kHz Dev.) S2:STEREO MOD., 400Hz, L or R=60%(40.5kHz+7.5kHz Dev.) NOTE:Before proceeding to further adjustments after switching power ON, let the tuner run for ten minutes to allow the circuits to stabilize. FM ADJUSTMENT FM SSG Displayed Adjustment Adjustment Method No. Frequency(MHz) Level(dBf) Frequency(MHz) Point (Switch Position) TUN Volt 1 ••••• ••••• 108.0 L5 DC V Meter(1) : 6V IF 2 98.1 M 60—100 98.1 T51 Center Meter : 0 ANT Coil 3 98.1 M 5 98.1 L2 mV Meter(1) : Maximum RF Coil 4 98.1 M 5 98.1 L4 mV Meter(1) : Maximum RF 5 129.3 M 60—80 107.9 TC1 mV Meter(1) : Minimum Trimmer 6 RF Coil and RF Trimmer shall be adjusted twice or more IFT 7 98.1 M 5 98.1 T31 mV Meter(1) : Maximum (STEREO MODE) ARC 8 98.1 S1 40 98.1 VR154 mV Meter(1) : Separation 5dB (STEREO MODE) RDS SL ADJUSTMENT FM SSG Displayed Adjustment Adjustment Method No. Frequency(MHz) Level(dBf) Frequency(MHz) Point (Switch Position) 1 104.0 S2 35 104.0 VR351 DC V Meter(2) : 1.75V+0.05V -0.35V www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 50 MEH-P5000R 6.2 MD MECHANISM MODULE ADJUSTMENT - About test disc Use a low reflection disc (MMD-211) for preliminary auto tuning (AUTO1). Use a high reflection disc (MMD-110), low reflection disc (MMD-211) for ATT auto tuning (AUTO2). Disc No. : TEAC MMD-211B or MMD-212B Tool No. : GGF1328 1. Be sure to perform “preliminary auto tuning” when you exchanged a PCB, Mechanism Unit, or Pickup Unit. 2. Let TP421 and TP435 (IC402: pin6, pin8) short circuited before preliminary auto tuning or overwriting EE-PROM (IC402) to clear protection on EE-PROM. * To overwrite EE-PROM, please see page 9 of the CX-893 Service Manual. MAIN PCB MD MECHANISM MODULE GGD1141 GGF1306 TUNER AMP UNIT CN201 GGD1118 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 51 MEH-P5000R - How to tune optical pick up grating Adjust Lissajous’ figure (x-y) of EOUT (TP131) to FOUT (TP130) after automatically adjusting in a test mode AUTO2 using a high reflection disc. 1. Loosen the three screws of the spinning motor and adjust checking Lissajous’ figure. 2. After the tuning is completed, tighten the screws 1, 2, and 3, in that order. 3. Check Lissajous’ figure again. - About tuning of jitter and how to tune it Use the following circuit as a tool to measure jitter. Check jitter value of EFM with the step continuous play in TESTPLAY mode after automatically tuning in a test mode AUTO2 (ATT auto tuning) using a low reflection disc. Check Lissajous’ figure while shifting positions to which the spinning motor is mounted. IC101 26pin EOUT IC101 25pin POUT TP201 EFMNON IC201 1pin Oscilloscope Lissajous’ figure Within the range a:b = 3:1 Jitter meter www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 52 MEH-P5000R Key name Outline of key operations BAND Used to power ON/OFF. ] Move through threads, jump, change settings, etc. [ Move through threads, jump, change settings, etc. ' Switch through MENU in the forward direction. Switch through MENU in the backward direction. SCR Switch to TEST STOP mode. FUNCTION Confirm the item you selected from MENU. - How to tune the position of read-in switch Check the sub code cluster value of the position of read-in switch in INNER mode. If the SUBQ value is outside the range between FF85 and FFD2, tighten the screws by shifting the mechanism PCB to the directions indicated with the arrow in the figure below, and then check the sub code cluster value of the position of read-in switch again. - Specifications of test mode operation Test mode is used to tune the MD player part in this model. • How to switch to test mode. Turn ACC and Back Up ON while holding down 4 key and 6 key. • How to deselect test mode. Turn ACC and Back Up OFF. Mechanism PCB Read-in switch Loosen the two screws Loosen the screws while tuning. ' www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 53 MEH-P5000R 6.2 MENU SWITCHING IN TEST MODE - Menus in Test Mode TEST STOP RIGHT LEFT "'" key in the main unit " " key in the main unit "'" key in the main unit "'" key in the main unit "'" key in the main unit "'" key in the main unit "'" key in the main unit "'" key in the main unit "'" key in the main unit "'" key in the main unit "'" key in the main unit " " key in the main unit " " key in the main unit " " key in the main unit " " key in the main unit " " key in the main unit " " key in the main unit " " key in the main unit " " key in the main unit " " key in the main unit AUTO1 AUTO2 RESULT1 RESULT2 MANUAL1 MANUAL2 ERR-DATA TEST PLAY EEPROM NORMAL INNER : Preliminary auto tuning menu : STOP test mode : ATT auto tuning checking menu : Preliminary auto tuning checing menu : ATT auto tuning checking menu : Preliminary manual tuning menu : ATT manual tuning menu : Error history displaying menu : Continuous playing menu : EEPROM setting menu : Test mode normal playing menu : INNER switch position measuring menu * Pressing "SCR" key in the main unit in each status switches to "TEST STOP" . Switch through outer circumference of slide Switch through inner circumference of slide ' ' ' ' ' ' ' ' ' ' " " key in the main unit ' www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 54 MEH-P5000R AUTO1 AT1 AT2 COMPLETE "F" key in the main unit "F" key in the main unit CANT-ADJ Tuning error Normal end : Preliminary auto tuning menu : Preliminary auto tuning is in progress : Preliminary tuning ends in an error : Preliminary tuning normally ends : ATT tuning is in progress * Pressing "SCR" key in the main unit in each status switches to "TEST STOP" . * " " is one of the following tuning numbers: 00 : Switch through most inner circumference 02 : Tentative measurement of ABEF offset 04 : Rough tuning of RF side focus gain 05 : Tentative setting of focus ATT 06 : Tuning of tracking gain in RF side pit part 07 : COUT level setting for tuning pit part 08 : Switch through outer circumference 09 : Tuning of tracking gain in RF side groove part 10 : COUT level setting for tuning groove part 11 : Tuning of RF side TCRS gain 12 : Initial setting of tracking ATT 13 : Fine tuning of RF side focus gain 14 : Initial setting of focus ATT 15 : Measurement of S gain "High" ABEF offset 16 : Measurement of TCRS offset 17 : Measurement of S gain "Low" ABEF offset - Preliminary auto tuning www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 55 MEH-P5000R AUTO2 AT2 SUBQ #### ADIP #### COMPLETE "F" key in the main unit "F" key in the main unit CANT-ADJ Tuning error Normal end : ATT auto tuning menu : ATT auto tuning is in progress : ATT tuning ends in an error : ATT tuning normally ends : Continuous playing (high reflection) : Continuous playing (low reflection) * Pressing "SCR" key in the main unit in each status switches to "TEST STOP" . * " " is one of the following tuning numbers: 00 : Switch through most inner circumference 03 : ATT setting of tracking in pit part 04 : ATT setting of focus in pit part 06 : Switch through outer circumference (low reflection only) 07 : ATT setting of TCRS (low reflection only) 08 : ATT setting of tracking in groove part (low reflection only) 09 : ATT setting of focus in groove part (low reflection only) - ATT auto tuning www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 56 MEH-P5000R MANUAL1 "F" key in the main unit PCH -- " " key in the main unit " " key in the main unit " " key in the main unit " " key in the main unit " " key in the main unit "'" key in the main unit "'" key in the main unit "'" key in the main unit "'" key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit : Temperature code display $$ : Temperature code : Preliminary manual tuning menu : Tentative setting of A signal offset (AINO) : Measured value : Tentative setting of B signal offset (BINO) : Measured value : Tentative setting of E signal offset (EINO) : Measured value : Tentative setting of F signal offset (FINO) : Measured value : Laser power on (Play power on) : Rough tuning of RF side focus gain : Setting value of gain : E-ATT (Tracking) initial setting ___ : ATT setting value : F-ATT (Tracking) initial setting ___ : ATT setting value : A-ATT (Focus) tentative setting ___ : ATT setting value : B-ATT (Focus) tentative setting ___ : ATT setting value : Tuning of tracking gain in RF side pit part : Setting value of gain : COUT level setting for tuning pit part -- : Setting value of COUT level : Tuning of tracking gain in RF side grove part : Setting value of gain : COUT level setting for tuning grove part -- : Setting value of COUT level : Tuning of RF side TCRS gain : Setting value of gain TMP $$ RFS GCH -- PTG SET ___ SFT ___ GTG RCG IAO IBO IEO IFO IAT ___ IBT ___ LON P ' ' ' ' ' ' ' ' ' ' ' ' ' ' ' ' - Preliminary manual tuning www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 57 MEH-P5000R * Pressing "SCR" key in the main unit in each status switches to "TEST STOP" . * Pressing "F" key in the main unit in each status where a setting value is displayed changes the digit of the setting value that will be changed. • When the setting value has two digits. "F" key in the main unit "F" key in the main unit The first digit (Initial value) The second digit "F" key in the main unit "F" key in the main unit "F" key in the main unit The first digit (Initial value) The second digit The third digit • When the setting value has three digits. * Pressing VOL UP/DOWN key in each status where a setting value is displayed changes the value in the digit you selected in the range from 0H through FH. However, the setting value of RF side gain changes in the range from 0H through 6H. " " key in the main unit "'" key in the main unit " " key in the main unit " " key in the main unit " " key in the main unit " " key in the main unit " " key in the main unit " " key in the main unit : Measurement of S gain "High" B signal offset (BINO) : Measured value : Measurement of S gain "High" E signal offset (EINO) : Measured value : Measurement of S gain "High" F signal offset (FINO) : Measured value : Measurement of TCRS signal offset (TCRSO) : Measured value : Measurement of S gain "Low" A signal offset (AINO) : Measured value : Measurement of S gain "Low" B signal offset (BINO) : Measured value : Measurement of S gain "Low" E signal offset (EINO) : Measured value HBO HEO HFO LAO LBO LEO : Measurement of S gain "Low" F signal offset (FINO) : Measured value LFO TCO "'" key in the main unit "'" key in the main unit "'" key in the main unit "'" key in the main unit "'" key in the main unit "'" key in the main unit -- *** ___ *** ___ *** ___ *** -- *** " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit : Fine tuning of RF side focus gain : Setting value of gain : A-ATT (Focus) initial setting ___ : ATT setting value : B-ATT (Focus) initial setting ___ : ATT setting value : Measurement of S gain "High" A signal offset (AINO) : Measured value SBT ___ HAO SAT ___ RFG ' ' ' ' ' ' ' " " key in the main unit ' ' ' ' www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com MEH-P5000R * Pressing RIGHT/LEFT key in each status where a setting value is displayed changes the value in the digit you selected in the range from 0H through FH. " " key in the main unit "F" key in the main unit "'" key in the main unit HBT ___ LBT ___ SUBQ #### ADIP #### * Pressing "SCR" key in the main unit in each status switches to "TEST STOP" status. * Pressing "F" key in the main unit in the B-ATT setting status switches to continuous play. Pressing "F" key in the main unit in the continuous playing status switches to the B-ATT setting status in the ATT manual tuning. : Setting of high reflection B-ATT (Focus) in pit part : Setting of low reflection B-ATT (Focus) in pit part : Setting of low reflection B-ATT (Focus) in groove part ___ : ATT setting value : Continuous play (pit part) #### : Address * Pressing "F" key in the main unit in each status where a setting value is displayed changes the digit of the setting value that will be changed. The first digit (Initial value) The second digit The third digit "F" key in the main unit "F" key in the main unit ___ *** ___ *** ___ *** ' "F" key in the main unit "'" key in the main unit "'" key in the main unit "'" key in the main unit "'" key in the main unit "'" key in the main unit "'" key in the main unit "'" key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit " " key in the main unit " " key in the main unit " " key in the main unit " " key in the main unit " " key in the main unit " " key in the main unit " " key in the main unit " " key in the main unit "'" key in the main unit : ATT manual tuning menu : Temperature code display $$ : Temperature code MANUAL2 : Laser power on (Play power on) : E-ATT (Tracking) setting of pit part ___ : ATT setting value : F-ATT (Tracking) setting of pit part ___ : ATT setting value : Setting of high reflection A-ATT (Focus) : Setting of low reflection A-ATT (Focus) ___ : ATT setting value : Setting of high reflection B-ATT (Focus) : Setting of low reflection B-ATT (Focus) ___ : ATT setting value : ATT setting of TCRS __ : ATT setting value : Setting of E-ATT (Tracking) in groove part ___ : ATT setting value : Setting of F-ATT (Tracking) in groove part ___ : ATT setting value : Setting of low reflection A-ATT (Focus) ___ : ATT setting value : Setting of low reflection B-ATT (Focus) ___ : ATT setting value PFT ___ LON P PET ___ HBT ___ LBS ___ GCT __ GET ___ GFT ___ LAT ___ LBT ___ TMP $$ HAT ___ LAS ___ ' ' ' ' ' ' ' ' ' ' - ATT manual tuning 58 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com MEH-P5000R "F" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit : Preliminary tuning checking menu : Measured value of S gain "High" A signal offset (Setting value) : Measured value of S gain "High" B signal offset (Setting value) : Measured value of S gain "High" E signal offset (Setting value) : Measured value of S gain "High" F signal offset (Setting value) : Measured value of S gain "Low" A signal offset (Setting value) : Measured value of S gain "Low" B signal offset (Setting value) : Measured value of S gain "Low" E signal offset (Setting value) : Measured value of S gain "Low" F signal offset (Setting value) : Measured value of TCRS signal offset : Measured value of tracking gain in RF side pit part : Measured value of RF side TCRS gain : Measured value of tracking gain in RF side groove part : Measured value of RF side focus gain : Setting value of COUT level for tuning pit part : Initial value of B-ATT (Focus) : Initial value of A-ATT (Focus) : Setting value of COUT level for tuning groove part : Initial value of E-ATT (Tracking) : Initial value of F-ATT (Tracking) HAO HBO HEO HFO LAO LBO LEO LFO SAT ___ SBT ___ SFT ___ TCO PCH -- GCH -- PTG GTG RCG RFG RESULT1 SET ___ ' ' ' ' ' ' ' ' ' ' ' ' ' ' ' ' ' ' - Checking preliminary tuned value 59 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 60 MEH-P5000R * Pressing "SCR" key in the main unit in each status switches to "TEST STOP" . * Pressing "F" key in the main unit in each status where a setting value is displayed changes the digit of the setting value that will be changed. • When the setting value has three digits. * Pressing VOL UP/DOWN key in each status where a setting value is displayed changes the value in the digit you selected in the range from 0H through FH. However, the setting value of RF side gain changes in the range from 0H through 6H. "F" key in the main unit The first digit (Initial value) The second digit The first digit (Initial value) The second digit The third digit "F" key in the main unit "F" key in the main unit "F" key in the main unit "F" key in the main unit • When the setting value has two digits. -- *** ___ *** ___ *** ___ *** -- *** www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 61 MEH-P5000R "F" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit : ATT value checking menu : Setting value of E-ATT (Tracking) in pit part : Setting value of F-ATT (Tracking) in pit part : Setting value of E-ATT (Tracking) in grove part : Setting value of F-ATT (Tracking) in grove part : Setting value of high reflection A-ATT (Focus) : Setting value of high reflection B-ATT (Focus) : Setting value of low reflection A-ATT (Focus) : Setting value of low reflection B-ATT (Focus) : Setting value of TCRS-ATT PET ___ PFT ___ GET ___ GFT ___ HAT ___ HBT ___ GCT __ RESULT2 * Pressing "SCR" key in the main unit in each status switches to "TEST STOP" . * Pressing "F" key in the main unit in each status where a setting value is displayed changes the digit of the setting value that will be changed. * Pressing RIGHT/LEFT key in each status where a setting value is displayed changes the value in the digit you selected in the range from 0H through FH. "F" key in the main unit The first digit (Initial value) The second digit The third digit "F" key in the main unit "'" key in the main unit • When the setting value has three digits. ___ *** ___ *** ___ *** LAT ___ LBT ___ ' ' ' ' ' ' ' ' - Checking ATT setting value www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 62 MEH-P5000R RIGHT : Continuous play menu : Continuous play menu : Continuous play (pit part) : Continuous play (groove part) #### : Address : Continuous play (pit part) : Continuous play (groove part) #### : Address : Continuous play (pit part) : Continuous play (groove part) #### : Address : B-ATT (Focus) setting of high reflection pit part : B-ATT (Focus) setting of low reflection pit part ___ : ATT setting value • When you start continuous play with the position which is picked up. SUBQ #### ADIP #### SUBQ #### ADIP #### TESTPLAY TESTPLAY ADRS0050 "F" key in the main unit " " key in the main unit "F" key in the main unit : Specify the address from which you start playing. • When you start continuous play with any address. SUBQ #### ADIP #### * Pressing "SCR" key in the main unit in each status switches to "TEST STOP" status. * Pressing "'" key in the main unit in the status where you specified the address to start playing switches the digit of the address that will be changed. * Pressing " " key in the main unit in the status where you specified the address to start playing switches the digit of the address as shown below. 0050H (Initial value) 03C0H 0700H 08A0H ADRS0050 ADRS03C0 ADRS0700 The first digit (Initial value) The second digit The third digit ADRS0050 ADRS0050 ADRS0050 ADRS08A0 * Pressing RIGHT/LEFT key in each the status where you specified the address to start playing switches the value in the digit you selected in the range from 0H through FH. * Pressing " " key in the main unit in the continuous play status switches to the B-ATT setting status in the ATT manual tuning. HBT ___ LBT ___ " " key in the main unit " " key in the main unit " " key in the main unit "'" key in the main unit "'" key in the main unit "'" key in the main unit "'" key in the main unit ' ' ' ' ' ' - Continuous play www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 63 MEH-P5000R "F" key in the main unit : INNER switch position measuring menu : Continuous play (pit part) #### : Address SUBQ #### INNER * Pressing "SCR" key in the main unit in each status switches to "TEST STOP" . "F" key in the main unit : Test mode normal playing menu : Normal play mode @@@@@@ : Mode and address @@ @@@@@ NORMAL * Pressing "SCR" key in the main unit in each status switches to "TEST STOP" . - Measuring the position of INNER switch - Test mode normal play "F" key in the main unit One (Initial value) 10 400 1T JMP 10T JMP 400T JMP * Pressing "F" key in the main unit in switches the number of trucks to be jumped as shown below. * Pressing RIGHT key in the continuous play status jumps the trucks by the number you specified in the direction of the outer circumference. * Pressing LEFT key in the continuous play status jumps the trucks by the number you specified in the direction of the inner circumference. "F" key in the main unit "F" key in the main unit www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 64 MEH-P5000R LEFT " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit "'" key in the main unit : Error history displaying menu : Clear error history SKIP UP SKIP DOWN CLEAR ERR DATA "F" key in the main unit : Error history displaying menu : Display error history 0 : Error code : Display error history 1 : Error code : Display error history 2 : Error code : Display error history 3 : Error code : Display error history 4 : Error code : Display error history 5 : Error code : Display error history 6 : Error code : Display error history 7 : Error code : Display error history 8 : Error code : Display error history 9 : Error code ER0 ER1 ER2 ER3 ER4 ER5 ER6 ER7 ER8 ER9 ERR DATA * Pressing "SCR" key in the main unit in each status switches to "TEST STOP" . • Clearing error history • Displaying error history ' ' ' ' ' ' ' ' - Displaying error history www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 65 MEH-P5000R "F" key in the main unit " " key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit : EEPROM setting menu : Focus setting menu : Control setting menu : Tuning setting menu : Digital EQ setting menu : Tracking setting menu : Slide setting menu : Spinning setting menu EEPROM Focus CONTROL ADJSET DEQSET TRKING SLED SPINDLE * Pressing "SCR" key in the main unit in each status switches to "TEST STOP" . ' ' ' ' ' ' ' - Setting EEPROM www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 66 MEH-P5000R "F" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit : Focus setting menu : Setting value of the gain constant for focus based loop filter (PIT) __ : Setting value : Setting value of the gain constant for focus based loop filter (GRV) __ : Setting value : The first setting value of the number specifying f for focus based loop filter __ : Setting value : The second setting value of the number specifying f for focus based loop filter __ : Setting value : Setting value of the hysteresis level to be detected in FZC __ : Setting value : Setting value of the hysteresis level to be detected in FOK __ : Setting value : Setting value of LPF factor during FOK generation __ : Setting value : Reserve for focus control __ : Setting value : Amplitude of focus search __ : Setting value : Setting value of wait time during feeding with auto focus __ : Setting value : Slope of focus search __ : Setting value FGP __ FGG __ FF1 __ FF2 __ FZHLEV__ FOKLEV__ FSRESV__ FOKLPF__ FSLEV __ WAITF __ FSSLP __ Focus * Pressing "SCR" key in the main unit in each status switches to "TEST STOP" . * Pressing RIGHT/LEFT key in each status switches the setting value in the range from 00H through FFH. (Upper limits depend on items.) ' ' ' ' ' ' ' ' ' ' - Setting focus www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 67 MEH-P5000R "F" key in the main unit he first digit (Initial value) The second digit "F" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit : Control setting menu : EEPROM version __ : Setting value : The number of accumulated sectors when voice starts. __ : Setting value : Setting value 3 for controlling __ : Setting value : Setting value 4 for controlling __ : Setting value : Setting value 5 for control __ : Setting value : Special mode select data __ : Setting value : Setting data related to controlling and others __ : Setting value : Monitor select data __ : Setting value EPVER __ STSDN __ CTRL3 __ CTRL4 __ CTRL5 __ SMODE __ MOSEL __ RVSEL __ CONTROL * Pressing "SCR" key in the main unit in each status switches to "TEST STOP" . * Pressing "F" key in the main unit in each status where a setting value is displayed changes the digit of the setting value that will be changed. * Pressing RIGHT/LEFT key in each status where a setting value is displayed changes the value in the digit you selected in the range from 0H through FH. "F" key in the main unit __ ***** __ ***** ' ' ' ' ' ' ' - Setting control www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 68 MEH-P5000R "F" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit : Environment setting menu : Reference value of COUT level for tuning __ : Setting value : Focus ATT reference value __ : Setting value : Tracking ATT reference value __ : Setting value : TCRS ATT reference value __ : Setting value : Focus balance factor __ : Setting value COKPL __ FATPL __ TATPL __ CATPL __ FABPL __ ADJSET * Pressing "SCR" key in the main unit in each status switches to "TEST STOP" . * Pressing "F" key in the main unit in each status where a setting value is displayed changes the digit of the setting value that will be changed. * Pressing RIGHT/LEFT key in each status where a setting value is displayed changes the value in the digit you selected in the range from 0H through FH. "F" key in the main unit The first digit (Initial value) The second digit "F" key in the main unit __ ***** __ ***** ' ' ' ' - Tuning setting www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 69 MEH-P5000R "F" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit : Digital EQ setting menu : Digital EQ tap factor A, D for high reflection pit part __ : Setting value : Digital EQ tap factor B, C for high reflection pit part __ : Setting value : Gain of auto level slicer for high reflection pit part __ : Setting value : Slice level offset of auto level slicer for high reflection pit part __ : Setting value : Digital EQ tap factor A, D for low reflection pit part __ : Setting value : Digital EQ tap factor B, C for low reflection pit part __ : Setting value : Slice level offset of auto level slicer for low reflection pit part __ : Setting value : Gain of auto level slicer for low reflection pit part __ : Setting value HQ1 __ HQ2 __ LQ1 __ LQ2 __ HSG __ HSO __ LSG __ LSO __ : Digital EQ tap factor A, D for low reflection groove part __ : Setting value : Digital EQ tap factor B, C for low reflection groove part __ : Setting value : Gain of auto level slicer for low reflection groove part __ : Setting value : Reverse switch of servo AD input __ : Setting value : Slice level offset of auto level slicer for low reflection groove part __ : Setting value GQ2 __ GQ1 __ GSO __ GSG __ ADPSW __ DEQSET * Pressing "F" key in the main unit in each status switches to "TEST STOP" . * Pressing "F" key in the main unit in each status where a setting value is displayed changes the digit of the setting value that will be changed. * Pressing RIGHT/LEFT key in each status where a setting value is displayed changes the value in the digit you selected in the range from 0H through FH. " " key in the main unit The first digit (Initial value) The second digit __ ***** __ ***** ' ' ' ' ' ' ' ' ' ' ' ' ' - Setting digital EQ www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 70 MEH-P5000R "F" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit : Spinning setting menu : Setting value of the gain constant for spin based loop filter __ : Setting value : Setting value of the gain constant for spin based loop filter (Inner circumference) __ : Setting value : Setting value of the gain constant for spin based loop filter (Mid circumference) __ : Setting value : Setting value of the gain constant for spin based loop filter (Outer circumference) __ : Setting value : The first setting value of the number specifying f for spin based loop filter __ : Setting value : The second setting value of the number specifying f for spin based loop filter __ : Setting value : The fourth setting value of the number specifying f for spin based loop filter __ : Setting value : The third setting value of the number specifying f for spin based loop filter __ : Setting value SPG __ SP1 __ SP2 __ SPGMID__ SPGOUT__ SPDLIM__ SP3 __ SP4 __ : The fifth setting value of the number specifying f for spin based loop filter __ : Setting value : Limiter setting value of spin drive PWM duty __ : Setting value : Initial kick level of spinning (duration) __ : Setting value : Interval between spinning and resuming __ : Setting value : Rotation kick level of spinning (time) __ : Setting value SP5 __ HCWLV __ HCCWL __ SPKT1 __ SPKT2 __ SPKT3 __ : Level to determine high speed forward rotation __ : Setting value : Level to determine high speed backward rotation __ : Setting value : KICK wait during high speed rotation __ : Setting value HWAIT __ : Reserve for spindle controlling __ : Setting value SPRSV __ SPGIN __ SPINDLE * Pressing "SCR" key in the main unit in each status switches to "TEST STOP" . * Pressing RIGHT/LEFT key in each status where a setting value is displayed changes the value in the digit you selected in the range from 0H through FH. (Upper limits depend on items.) ' ' ' ' ' ' ' ' ' ' ' ' ' ' ' ' - Setting spinning www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com MEH-P5000R "F" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit : Tracking setting menu : Setting value of the gain constant for tracking based loop filter (PIT) __ : Setting value : Setting value of the gain constant for tracking based loop filter (GRV) __ : Setting value : The first setting value of the number specifying f for spin based loop filter __ : Setting value : The second setting value of the number specifying f for spin based loop filter __ : Setting value TGP __ TGG __ TF1 __ TF2 __ TRBLV___ TRBLVT__ TRKLVO__ TRKLVT__ : Nonslid time setting for jumping over ten trucks __ : Setting value : Nonslid time setting for jumping over one truck __ : Setting value : Tracking filter switch __ : Setting value : Break level setting for jumping over ten trucks __ : Setting value : Break level setting for jumping over one truck __ : Setting value : Kick pulse level setting for jumping over one truck __ : Setting value : Kick pulse level setting for jumping over ten trucks __ : Setting value : Drive pulse width time setting for jumping over one truck __ : Setting value : Drive pulse width time setting for jumping over ten trucks __ : Setting value : Move nonslid time setting __ : Setting value : PWM output offset setting __ : Setting value : Comparison level setting value during COUT generation __ : Setting value : TCRSC0 level setting (pit part) __ : Setting value : TCRSC0 level setting (groove part) __ : Setting value TRKING * Pressing "SCR" key in the main unit in each status switches to "TEST STOP" . * Pressing RIGHT/LEFT key in each status where a setting value is displayed changes the value in the digit you selected in the range from 00H through FFH. (Upper limits depend on items.) SVCT4 __ DBOFST__ TCSC0P__ TCSC0G__ : TCRSC1 level setting (pit part) __ : Setting value TCSC1P__ COTLV __ SLCTO __ SLCTT __ SLCTM __ TDPWO __ TDPWT __ ' ' ' ' ' ' ' ' ' ' ' ' ' ' ' ' ' ' - Setting tracking 71 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 72 MEH-P5000R "F" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit " " key in the main unit "'" key in the main unit : Slide setting menu : Thread gain constant __ : Setting value : Slide filter factor 2 __ : Setting value SLG __ SL2 __ SLDLIM__ SLDLEV__ SLKLVK__ SLKLVT__ SLKLVM__ : Supplementary feeding time for jumping over ten trucks __ : Setting value : Break setting during feeding through inner circumference __ : Setting value : Move overrun table 1 __ : Setting value : Slide output limiter __ : Setting value : Slide output dead zone __ : Setting value : Kick level for jumping over ten trucks __ : Setting value : Kick level during compelled slide move __ : Setting value : Kick level during move __ : Setting value : Feed wait time after move __ : Setting value : Minimum number of move trucks to be started __ : Setting value : Move overrun table 2 __ : Setting value : PIT GRV feeding time __ : Setting value : Thread control reserve __ : Setting value SLED * Pressing "SCR" key in the main unit in each status switches to "TEST STOP" . * Pressing RIGHT/LEFT key in each status where a setting value is displayed changes the value in the digit you selected in the range from 00H through FFH. (Upper limits depend on items.) SLRBK __ SLKTMT__ SLKTMF__ SLRESV__ MOVR1 __ MOVR2 __ WAITM __ MVMIN __ ' ' ' ' ' ' ' ' ' ' ' ' ' ' - Setting slide www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 73 MEH-P5000R 7. GENERAL INFORMATION 7.1 PARTS 7.1.1 IC VDA 24 25 Bip - + Z ADD SUB (12) I/O-3 9 10 I/O-2 FMOUT 27 IN HS - + NC AMTV 30 - + Bip 12bit AMIN 32 33 - + 34 PD1 PD REF 36 X-GND XI 39 38 Z (X-Y) LDET MODE SW (12) P(12) 8bit SHIFT IF FM 7 8 4 5 FM VCO AM VCO I/F 40 CE 41 DI 42 CK 43 DO 2 NC NC 1 (14) 37 XIO SR 44 28 29 FMIN 11 DA(12) DAC (12bit) Vref - NC 23 + VCO SUB (14) X Y CRESET IN3 REG (22bit) A-GND VDD 6 PD0 VREF2 MOS Bip I/O-1 VREF2 VREFP 17 18 IF 35 VREF2 MOS OUT AM 12 13 14 15 16 I/O-5 I/O-4 NC O-7 O-6 CUR REQUEST 20 LDET 21 22 19 VCC OUT1 SEL OUT2 SEL IN1 REG (31bit) (16) (4) 31 DIVIDER 4 BIT SHIFT 4 2 1 1 12bit REG PROGRAMABLE DIVIDER NC COUNTER 3 D-GND NC DATA REGISTER 26 IF AM COUNTER VCC BAND GAP FMTV Bip + 12bit SRx4 (12) (12) TVMEMORY SEL X Y PD & LDET - NC 14k 28k 35k 10k UCOM PM2007A PM2007A PD4960A PD6277A LC75874W PML003AM 1245730345 1245730449 1245730308 1245730310 1245730313 1245730086 1245730184 1245730631 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 74 MEH-P5000R - Pin Functions (PD4960A) Pin No. Pin Name I/O Function and Operation 1 SWVDD O Keyboard unit power supply control output 2 dsens I Grille detach sense input 3 NC Not used 4 isens I Illumination power supply sence input 5 TESTIN I Test program mode input 6 drst O RDS decoder reset output 7 NC Not used 8 sk I SK signal input 9,10 NC Not used 11 reset I Reset input 12 XT2 Not used 13 XT1 Not used 14 VSS GND 15 X2 Crystal oscillator connection pin 16 X1 Crystal oscillator connection pin 17 REGOFF Not used 18 REGC Not used 19 VDD Power supply 20 ILMPW O Illumination power supply control output 21 SYSPWR O System power control output 22 adpw O A/D converter power supply control output 23 LCDPW O LCD back light power supply control output 24 IPPW O Power supply control output for IP BUS interface IC 25 ASENBO O Slave power supply control output 26 AMPW O AM power supply control output 27 TELIN I Telephone mute input 28 mute O System mute output 29 DIM O Dimmer select output 30 FMPW O FM power supply control output 31,32 NC Not used 33 VCK O Clock output for electronic volume 34 VST O Strobe pulse output for electronic volume 35 VDT O Data output for electronic volume 36 tmute O Tuner mute output 37 DRELAY O External relay output 38 SD I Station detector input 39 st I FM stereo input 40 VSS GND 41 VDD Power supply 42 mdsens I RDS modulation detect input 43 NC Not used 44 rdslk I RDS LK signal input 45 currq O RDS tuning voltage FIX output 46 RDT I RDS Fdata input 47 NC Not used 48 DRSENS I Door open/close sense input 49 DRSYS O Door system select output 50 DLED O Alarm LED output 51 DALMON O DFS alarm output 52–61 NC Not used 62 PCL O Clock adjustment output 63 brxen I/O P-BUS reception enable input/output 64 bsrq I P-BUS service request output pin 65 BSCK I/O P-BUS serial clock input/output 66 BSI I P–BUS serial data input 67 BSO O P–BUS serial data output 68 brst I P–BUS reset input www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 75 MEH-P5000R Pin No. Pin Name I/O Function and Operation 69–72 NC Not used 73 TEST I Test terminal 74 SL I Signal level input from tuner 75 MODEL I Model select input 76 CL I Synchronizing signal input of display data latch 77 NL I RDS noise level input 78–81 NC Not used 82 AVDD A/D converter power supply 83 AVREF1 A/D converter reference voltage 84 GND A/D converter GND 85 RX I IP BUS data input 86 TX O IP BUS data output 87 GND GND 88 ldet I RDS PLL lock sense input 89 rck I RDS demodulation clock input 90 RDS57K I RDS 57kHzBP-OUT sense input 91 GND GND 92 asens I ACC power sense input 93 bsens I Back up power sense input 94 TUNPDI I PLL IC data input 95 KYDT I Key data input 96 DPDT O Display data output 97 TUNPCK O Serial clock output for PLL IC 98 TUNPDO O Data output for PLL IC 99 TUNPCE O Chip enable output for PLL IC 100 PEE O Beep tone output 30 31 50 51 80 81 100 1 *PD4960A IC's marked by* are MOS type. Be careful in handling them because they are very liable to be damaged by electrostatic induction. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 76 MEH-P5000R - Pin Functions (LC75874W) Pin No. Pin Name I/O Function and Operation 1–64 SE3-66 O LCD segment signal output 65–68 CO1-CO4 O LCD common signal output 69 VDD Power supply 70 VLCD LCD Power supply 71 VLCD1 LCD bias power supply 72 VLCD2 LCD bias power supply 73 VSS GND 74 OSC I/O 75 linh I Inhibit input from IC901 76 CE I Chip enable output pin for LCD driver 77 CL I Clock output for LCD driver 78 DI I Data output for LCD driver 79,80 SE1,SE2 O LCD segment signal - Pin Functions (PD6277A) Pin No. Pin Name I/O Format Function and Operation 1 VSS GND 2 X1 Crystal oscillator connection pin 3 X0 Crystal oscillator connection pin 4 reset I System reset input 5 MOD1 I Operation mode appointment input 6 MOD0 I Operation mode appointment input 7 LED O C LED control output 8 S0 O C System micro computer UART communication data output 9 S1 I System micro computer UART communication data input 10 REM I Remote control reception input 11 dim O C Dimmer output 12 ILM O C Illumination color select output 13–16 kd$–kd! I Key data input 17–22 kst^–! O C Key strobe output 23 VCC Power supply 24 inh O N LCD driver display inhibit output 25 CE O N Chip enable output for display driver 26 CL O N Synchronizing signal output for display driver 27 DI O N Data output for display driver 28–73 SEG45-0 O L LCD segment output 74–77 COM3–0 O L LCD common output 78 V3 LCD drive power supply 79 V2 LCD bias power supply 80 V1 LCD bias power supply *PD6277A 20 21 40 41 60 61 80 1 Format Meaning C C MOS N N channel open drain L LCD C output www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 77 MEH-P5000R PML003AM 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 Vref IN1_L IN2_L IN3_L IN4+_L AGND Loud- out_L SVin_L Front- out_L Rear- out_L FIE_L DGND IN4-_L CLK VCC IN1_R IN2_R IN3_R IN4+_R AGND Loud- out_R SVin_R Front- out_R Rear- out_R FIE_R STB IN4-_R DATA Isolator circuit Primary volume Anti Alias filter Treble Anti radiation filter Middle Bass Loudness volume FIE Fader volume Secondary volume Zero cross detect circuit Primary volume Anti Alias filter Middle Treble Bass Isolator circuit Anti radiation filter Loudness volume Zero cross detect circuit Fader volume Secondary volume FIE Digital block Auto-Zero Auto-Zero LC75874W 20 21 40 41 60 61 80 1 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 78 MEH-P5000R - Pin Functions (1245730345) Pin No. Pin Name I/O Function and Operation 1-4 RF1-4 I RF signal input terminals 1-4 Input RF signal output from pickup 5 REFI I Reference voltage amplifier input 6 REFO O Reference voltage amplifier output 7 RFADD O Terminal outputting added resistance of RF 1-4 8 TCGI I Terminal amplified inputting track cross detected signal at groove 9 AIN I Inverted input terminal of signal amplifier for the servo (Focus servo based) 10 BIN I Inverted input terminal of signal amplifier for the servo (Focus servo based) 11 EIN I Inverted input terminal of signal amplifier for the servo (Tracking servo based) 12 FIN I Inverted input terminal of signal amplifier for the servo (Tracking servo based) 13 BIAS I Bias input 14 AVCC Analog power supply 15 XSTBY O Logic signal outputting terminal (Outputs inverted STBY signal ) 16 XDISC O Logic signal outputting terminal (Outputs inverted DISC signal ) 17 XGAIN O Logic signal outputting terminal (Outputs inverted SGAIN signal ) 18 AGND Analog GND 19 DGND Digital GND 20 DTEMP I Chip temperature detection 21 LATCH I Latch signal input 22 CLOCK I Clock signal input 23 DATA I Serial data input 24 DVCC Digital GND 25 FOUT O Output terminal of signal amplifier for the servo (Tracking servo based) 26 EOUT O Output terminal of signal amplifier for the servo (Tracking servo based) 27 BOPUT O Output terminal of signal amplifier for the servo (Focus servo based) 28 AOUT O Output terminal of signal amplifier for the servo (Focus servo based) 29 TCGO O Terminal amplified inputting tracking cross detected signal at groove 30 WBO O Converter output terminal for ADIP signal binarization 31 22KI I Converter input terminal for ADIP signal trinarization 32 22KO O ADIP signal HPF amplifier output 33 ADLPFO O ADIP signal LPF amplifier output 34 NC Not used 35 ADIPO O ADIP signal pre-amplifier output 36 ADIPI O ADIP signal AGC amplifier output 37 ADAGC ADIP signal AGC smoothing capacitor connection pin 38 ADAGI I ADIP signal AGC amplifier input 39 RF2-1 Differential signal of RF1 and RF2 40 EFMO O RF signal pre-amplifier output 41 EFMI O RF signal AGC amplifier output 42 AVCC Analog power supply 43 AGND Analog GND 44 EFMAGC EFM signal AGC smoothing capacitor connection pin 45 EFMAGI I EFM signal AGC amplifier input 46 ATTR 47and 48 pin output signal attenuation terminal 47 GOUT O Outputs RF1+RF2+RF3-RF4 signal at groove 48 ROUT O Outputs added resistance of RF1-4 at PIT www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 79 MEH-P5000R 1245730345 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com MEH-P5000R - Pin Functions (1245730449) Pin No. Pin Name I/O Function and Operation 1 EFMMON O EFM monitor output 2 AVCC Analog power supply 3 EFMI I EFM signal input from RF AMP 4 AGND Analog GND 5 AIN I Focus error signal A 6 EIN I Tracking error signal E 7 TCG I Tracking cross signal 8 BIN I Focus error signal B 9 FIN I Tracking error signal F 10 VBAT I Power supply voltage detection signal for constant voltage servo 11 WBI I ADIP wobble signal 12 VDD1 Digital power supply 13 DGND Digital GND 14,15 TEST0,1 I Test input normality : GND 16 TEST2 I Test input en-deco/servo mode, ATRAC mode select normality : GND 17 X176KO O Clock output f=176.4KHz (4fs) 18 FODRF O Focus servo forward output PWM 19 FODRR O Focus servo reverse output PWM 20 TRDRF O Tracking servo forward output PWM 21 TRDRR O Tracking servo reverse output PWM 22 SLDRF O Slide servo forward output PWM 23 SLDRR O Slide servo reverse output PWM 24 SPDRF O Spindle servo forward output or spindle servo output PWM 25 SPDRR O Spindle servo reverse output or spindle rotary FWD/REV select 26-28 RAA3-1 O Address output to external D-RAM ADR3-1 29 RAA0 O Address output to external D-RAM ADR0 (LSB) 30 RAA10 O Address output to external D-RAM ADR10 (MSB) 31 VDD2 D-RAM interface power supply 32-36 RAA4-8 O Address output to external D-RAM ADR4-8 37 RA0EX O Data output enable signal to external D-RAM 38 DGND Digital GND 39 RACASX O Column address strobe signal output to external D-RAM 40 RAD2 I/O Data input/output with external D-RAM D2 41 RAD3 I/O Data input/output with external D-RAM D3 (MSB) 42 RAA9 O Address output to external D-RAM ADR9 43 RARASX O Row address strobe signal output to external D-RAM 44 RAWEX O Data write enable signal output to external D-RAM 45 RAD1 I/O Data input/output with external D-RAM D1 46 RAD0 I/O Data input/output with external D-RAM D0 (LSB) 47 TCRS O Track cross signal 48 ACRCER O ADIP CRC error flag monitor output 49 PLCK O EFM PLL clock output at playback 50 EFMO O Outputs EFM signal when recording Outputs C1F (C1 error flag) monitor when playbacking 51 X700KO O Clock output f=705.6KHz Dose not output clock when RSTX=0 52,53 EXPORT0,1 O Microprocessor extended output port 0,1 54 TESO1 O PLLLR Microprocessor extended output port 2 when switching 55 TEST3 I/O PLLOSC Microprocessor extended output port 3 when switching 56 TEST4 I/O EXTCLK Microprocessor extended output port 4 when switching 57 CDDATA I/O Inputs CD data for high speed dubbing Microprocessor extended output port 5 when switching 58 CDLRCK I/O Inputs CD LR clock for high speed dubbing Microprocessor extended output port 6 when switching 59 CDBCLK I/O Inputs CD bit clock for high speed dubbing Microprocessor extended output port 7 when switching 60 VXI I Inputs PLL clock for varipitch 61 VPO O Outputs PLL phase error for varipitch 62 VDD1 Digital power supply 63 DGND Digital GND 80 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 81 MEH-P5000R Pin No. Pin Name I/O Function and Operation 64 XI I Inputs oscillator 33.8688MHz 65 XO O Outputs oscillator 33.8688MHz 66 DIN I Digital input signal 67 DOUT O Digital output signal 68 VDD3 Internal PLL power supply 69 DGND Digital GND 70 LRCK O Lch/Rch select output of audio data 71 BCLK O Shift clock of audio data 72 DFCK O AD/DA converter digital filter clock 256Fs 73 ADDATA I Audio data input 74 DADATA O Audio data output 75 FEMON O Focus error signal monitor output 76 TOTMON O Total signal monitor output 77 TEMON O Tracking error signal monitor output 78 SBCK I DIN subcode read clock EIAJ CP-309 format 79 SBO O DIN subcode read serial data EIAJ CP-309 format 80 SBSY O DIN subcode block synchronizing signal CP-309 format 81 SFSY O DIN subcode frame synchronizing signal CP-309 format 82 FOK O Focus OK detection signal "0" : Focus OK 83 SENSE O Servo condition detection signal "1": During pull in auto move, auto jump, auto focus 84 COUT O Track cross signal output 85 MCCK O Clock output for microcomputer Outputs clock when RSTX=0 86 DINTX O Interrupt request output to system control interface 87 VDD1 Digital power supply 88 DGND Digital GND 89 RSTX I Chip reset input L : Reset 90-97 SYD0-7 I/O System control interface data bus 98 SYWRX I System control interface register write pulse input 99 SYRDX I System control interface register read pulse input 100 SYRS I System control interface register select input 1245730449 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 82 MEH-P5000R 1245730308 1G 1 1A 2 1Y 3 2G 4 2A 5 2Y 6 GND 7 14 Vcc 13 4G 12 4A 11 4Y 10 3G 9 3A 8 3Y 5 Vcc A 1 B 2 GND 3 4 C 8 Vcc 7 2G 6 1Y 5 2A 1G 1 1A 2 2Y 3 GND 4 1245730310 1245730313 1245730086 4 3 2 1 5 6 7 8 1105730631 1 2 3 4 5 6 7 8 9 10 20 19 18 17 16 15 14 13 12 11 Vss I/04 I/03 /CAS /OE A8 A7 A6 A5 A4 I/01 I/02 /WE /RAS A9 A0 A1 A2 A3 Vcc www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 83 MEH-P5000R - Pin Functions (1245730184) Pin No. Pin Name I/O Function and Operation 1 GND Pre part GND 2 VG Gate voltage supply 3 IN4R I CH4 reverse input 4 IN4F I CH4 forward input 5 VM4 Power part power supply 6 OUT4F O CH4 forward output 7 PGND4 Power part GND 8 OUT4R O CH4 reverse output 9 VM34 Power part GND 10 OUT3R O CH3 reverse output 11 PGND3 Power part GND 12 OUT3F O CH3 forward output 13 VM3 Power part power supply 14 IN3F I CH3 forward input 15 IN3R I CH3 reverse input 16 PSB Power off 17 VDD Pre part power supply 18 IN1R I CH1 reverse input 19 IN1F I CH1 forward input 20 VM1 Power part power supply 21 OUT1F O CH1 forward output 22 PGND1 Power part GND 23 OUT1R O CH1 reverse output 24 VM12 Power part power supply 25 OUT2R O CH2 reverse output 26 PGND2 Power part GND 27 OUT2F O CH2 forward output 28 VM2 Power part power supply 29 IN2F I CH2 forward input 30 IN2R I CH2 reverse input 31,32 NC Not used 1 16 17 32 1245730184 www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 84 MEH-P5000R 7.1.2 DISPLAY - CAW1490 COMMON SEGMENT www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 7.2 DIAGNOSIS 7.2.1 DISASSEMBLY - Removing the Case Unit(not shown) 1. Remove the two screws. 2. Insert and turn a flat screwdriver to remove the case unit. - Removing the Detach Grille Assy 1. Press the detach button, and then remove the detach grille assy. - Removing the Panel Assy 1. Disconnect the two stoppers, and then remove the panel assy. - Removing the MD Mechanism Module 1. Remove the four screws A. 2. Disconnect the connector indicated by arrow. 3. Remove the MD Mechanism Module. - Removing the Tuner Amp Unit 1. Remove the four screws B, two screws C and two screws D 2. Unbend the tabs at two locations indicated by arrows. 3. Remove the Tuner Amp Unit. 85 MEH-P5000R A A A A MD Mechanism Module Detach Grille Assy Detach Button Panel Assy D D B B B B C C Tuner Amp Unit Chassis Unit www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 86 MEH-P5000R 7.3 EXPLANATION 7.3.1 BLOCK DIAGRAM B A D E F TUNER AMP UNIT FM/AM TUNER UNIT MAIN PCB OPTICAL PICKUP ASSY MECHANISM PCB SWITCH PCB www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 87 MEH-P5000R C KEYBOARD UNIT www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 88 MEH-P5000R 8. OPERATIONS AND SPECIFICATIONS 8.1 OPERATIONS Key Finder Head Unit Remote Controller (CD-R66) The remote controller (CD-R66) enabling remote control of the head unit is sold separately. Operation is the same as when using buttons on the head unit. FUNCTION button AUDIO button +/– button 5/∞/2/3 buttons BAND button PGM button CD button Press once to select a CD. ATT button This lets you quickly lower volume level (by about 90%). Press once more to return to the original volume level. TUNER button Press once to select the tuner. TAPE button Press once to select an MD. PTY button Buttons 1 – 6 TA button EJECT button Disc loading slot AUDIO button 5/∞/2/3 buttons FUNCTION button SOURCE button +/– button BAND button DISP button DETACH button SCROLL button EQ button www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 89 MEH-P5000R Basic Operation To Listen to Music The following explains the initial operations required before you can listen to music. Note: • Loading a disc in this product. 1. Select the desired source (e.g. tuner). 7 Head Unit Each press of the SOURCE button selects the desired source in the following order: Tuner = Built-in MD player = Multi-MD player = Multi-CD player = AUX 7 Remote Controller Each press of the button selects the desired source in the following order: TUNER button : Tuner = Sources OFF CD button : Multi-CD player = Sources OFF TAPE button : Built-in MD player = Multi-MD player = AUX = Sources OFF Note: • In the following cases, the sound source will not change: * No Multi-CD player is connected to this product. * No Multi-MD player is connected to this product. * No disc is set in this product. * No magazine is set in the Multi-CD player. * No disc is set in the Multi-MD player. * AUX (external input) is set to OFF. Each press changes the Source ... 2. Raise or lower the volume. 3. Source OFF. Hold for 1 second or more www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 90 MEH-P5000R Basic Operation of Tuner This product’s AF function can be switched ON and OFF. AF should be switched OFF for normal tuning operations. Manual and Seek Tuning • You can select the tuning method by changing the length of time you press the 2/3 button. Manual Tuning (step by step) 0.5 seconds or less Seek Tuning (automatically) Press for 0.5 seconds or more and then release. Manual Tuning (continuously) Continue pressing for 0.5 seconds or more without releasing. (When you release the button, Seek Tuning is selected.) Note: • “” stereo indicator lights when a stereo station is selected. Preset Tuning • You can memorize broadcast stations in buttons 1 through 6 for easy, one-touch station recall. Preset station recall 2 seconds or less Broadcast station preset memory 2 seconds or more Note: • Up to 18 FM stations (6 in F1 (FM1), F2 (FM2) and F3 (FM3)) and 6 MW/LW stations can be stored in memory. • You can also use the 5 �or ∞ buttons to recall broadcast stations memorized in buttons 1 through 6. Frequency Indicator Band Indicator Band F1 (FM1) = F2 (FM2) = F3 (FM3) = MW/LW Preset Number Indicator www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 91 MEH-P5000R Basic Operation of Built-in MD Player Track Search and Fast Forward/Reverse • You can select between Track Search or Fast forward/Reverse by pressing the 2/3 button for a different length of time. Track Search 0.5 seconds or less Fast forward/Reverse Continue pressing Note: • When you load a disc, this unit reads information recorded on the disc such as the number of tracks. While the disc is being read, “TOC READ” is indicated in the display. • If you load a disc with the arrow pointing in the wrong direction, it is automatically ejected. • If the built-in MD player cannot operate properly, an error message (such as “ERROR-11”) appears on the display. Disc Loading Slot You can only load one MD at a time in the built-in MD player. Load the MD in the direction of the arrow, with the label side facing up. Note: • Load an MD after confirming the MD shutter is closed. Eject Note: • The MD function can be turned ON/OFF with the disc remaining in this product. • Discs left partially inserted after ejection may incur damage or fall out. Elapsed Play Time Indicator Track Number Indicator Switching the Display Each press of the DISP button changes the display in the following order: Playback mode (Elapsed play time) = Disc Title = Track Title Scrolling the Display Displayed disc and track names are only up to 10 letters long, but indications can be scrolled. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 92 MEH-P5000R Basic Operation of Multi-CD Player This product can control one or more multi-CD players. (There are some types of Multi- CD players such as CDX-P630S which you cannot connect more than one.) Track Search and Fast Forward/Reverse • You can select between Track Search or Fast forward/Reverse by pressing the 2/3 button for a different length of time. Track Search 0.5 seconds or less Fast forward/Reverse Continue pressing Elapsed Play Time Indicator Disc Search Disc Number Indicator Track Number Indicator Switching the Multi-CD Player Using a multiple connection adapter lets you connect up to three Multi-CD players. M-CD 1 = M-CD 2= M-CD 3 (Displayed about for 2 seconds.) Switching the Display Each press of the DISP button changes the display in the following order: Playback mode (Elapsed play time) = Disc Title www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 93 MEH-P5000R Disc Number Search (for 6-Disc, 12-Disc types) • You can select discs directly with the 1 to 6 buttons. Just press the number corresponding to the disc you want to listen to. Note: • When a 12-Disc Multi-CD Player is connected and you want to select disc 7 to 12, press the 1 to 6 buttons for 2 seconds or longer. Disc Number Rough Search (for 50-Disc type only) This handy function lets you select discs loaded in a 50-Disc Multi-CD Player using the 1 to 5 buttons. The 50 discs are divided into five blocks, with each of the 1 to 5 buttons assigned to a block. • Select the desired block with the 1 to 5 buttons. Note: • After completing a rough search, use the 5 and ∞ buttons to select a desired disc. Note: • If you switch displays when disc titles have not been input, “NO TITLE” is displayed . • The multi-CD player may perform a preparatory operation, such as verifying the presence of a disc or reading disc information, when the power is turned ON or a new disc is selected for playback. “READY” is displayed. • When a magazine is loaded into a 50-Disc type Multi-CD Player, information on all the discs in the magazine is read. If you start playing a disc on a 50-Disc type Multi-CD Player before reading of information on all discs has been completed, reading of information stops part way through. This will prevent you from using a number of functions. (If you try and use these functions, “NOT READY” is displayed.) If this happens, reading of information begins again when you switch to a component other than the 50-Disc type Multi-CD Player. • If the multi-CD player cannot operate properly, an error message such as “ERROR-14” is displayed. Refer to the multi-CD player owner’s manual. • If there are no discs in the multi-CD player magazine, “NO DISC” is displayed. • “LOAD” will be displayed in the following cases: * If the disc in the extra tray in selected. * If the disc in moved from the extra tray to the magazine. (Refer to the 50-Disc type multi-CD player owner’s manual.) • You cannot use the “Ejecting a Single Disc”, “Frequency Play”, “Music Group Play” or “ABC Disc Title Search” functions with this unit. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 94 MEH-P5000R + ≠ + ≠ Note: Depending on the kind of vehicle, the function of 3* and 5* may be different. If this is the case, be sure to connect 2* to 5* and 4* to 3*. + ≠ + ≠ Use this for connections when you have the separately available amplifier. Speaker leads Rear Connecting cords with RCA pin plugs (sold separately) Cap (1*) When not using this terminal, do not remove the cap. ISO connector Blue/white Rear output Fuse holder 1* 2* 4* 3* 5* White/yellow Antenna jack Yellow (2*) To terminal always supplied with power regardless of ignition switch position. Red (4*) To electric terminal controlled by ignition switch (12 V DC) ON/OFF. Yellow (3*) Back-up (or accessory) Red (5*) Accessory (or back-up) Black (ground) To vehicle (metal) body. Orange To lighting switch terminal. Blue/white To Auto-antenna relay control terminal. (Max. 300 mA 12 V DC.) Connect leads of the same color to each other. Note: In some vehicles, the ISO connector may be divided into two. If this is the case, be sure to connect to both connectors. See the section “RFP Alert Installation”. Power amp (sold separately) Blue/white To system control terminal of the power amp. (Max. 300 mA 12 V DC.) Rear White White/black Gray Gray/black Green Green/black Violet Violet/black : Front left + : Front left ≠ : Front right + : Front right ≠ : Rear left + : Rear left ≠ : Rear right + : Rear right ≠ Left speaker Right speaker Multi-CD player (sold separately) IP-BUS input (Blue) IP-BUS cable This Product Front Front Blue/white Power amp (sold separately) Front output Yellow/black If you use a cellular telephone, connect it via the Audio Mute lead on the cellular telephone. If not, keep the Audio Mute lead free of any connections. CAUTION • Cords for this unit and those for other units may be different colors even if they have the same function. When connecting this unit to another unit, refer to the supplied Installation manuals of both units and connect cords that have the same function. www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com 95 MEH-P5000R General Power source .......... 14.4 V DC (10.8 – 15.1 V allowable) Grounding system ........................................ Negative type Max. current consumption ...................................... 10.0 A Dimensions (mounting size) ...... 178 (W) ´ 50 (H) ´ 150 (D) mm (front face) .............. 188 (W) ´ 58 (H) ´ 18 (D) mm Weight ...................................................................... 1.3 kg Amplifier Maximum power output ...................................... 40 W ´ 4 Continuous power output .................................... 25 W ´ 4 (DIN45324, +B = 14.4 V) Load impedance .......................... 4 W (4 – 8 W allowable) Preout output level/output impedance ........ 500 mV/1 k½ Equalizer (3-Band Parametric Equalizer) (Low) .......................... Frequency: 40/80/100/160 Hz Q Factor: 0.35/0.59/0.95/1.15 (+6 dB when boosted) Level: ±12 dB (Mid) .......................... Frequency: 200/500/1k/2k Hz Q Factor: 0.35/0.59/0.95/1.15 (+6 dB when boosted) Level: ±12 dB (High) ................ Frequency: 3.15k/8k/10k/12.5k Hz Q Factor: 0.35/0.59/0.95/1.15 (+6 dB when boosted) Level: ±12 dB Loudness contour (Low) .................. +3.5 dB (100 Hz), +3 dB (10 kHz) (volume: –30 dB) (Mid) ................ +10 dB (100 Hz), +6.5 dB (10 kHz) (volume: –30 dB) (High) ................ +11 dB (100 Hz), +11 dB (10 kHz) (volume: –30 dB) MD player System ................................ Mini disc digital audio system Usable discs ........................................................ Mini disc Signal format .................... Sampling frequency: 44.1 kHz Number of quantization bits: 16; linear Frequency characteristics ............ 20 – 20,000 Hz (±1 dB) Signal-to-noise ratio ...... 94 dB (1 kHz) (IEC-A network) Dynamic range ............................................ 93 dB (1 kHz) Number of channels ............................................ 2 (stereo) FM tuner Frequency range ...................................... 87.5 – 108 MHz Usable sensitivity .................. 11 dBf (1.0 mV/75 W, mono, S/N: 30 dB) 50 dB quieting sensitivity .... 16 dBf (1.7 mV/75 W, mono) Signal-to-noise ratio ...................... 70 dB (IEC-A network) Distortion .......................... 0.3% (at 65 dBf, 1 kHz, stereo) Frequency response ...................... 30 – 15,000 Hz (±3 dB) Stereo separation .......................... 40 dB (at 65 dBf, 1 kHz) MW tuner Frequency range ...................................... 531 – 1,602 kHz Usable sensitivity .............................. 18 mV (S/N: 20 dB) Selectivity .................................................. 50 dB (±9 kHz) LW tuner Frequency range ........................................ 153 – 281 kHz Usable sensitivity .............................. 30 mV (S/N: 20 dB) Selectivity .................................................. 50 dB (±9 kHz) Note: • US and foreign patents licensed from Dolby Laboratories Licensing Corporation. • Specifications and the design are subject to possible modification without notice due to improvements. 8.2 SPECIFICATIONS www. xiaoyu163. com QQ 376315150 9 9 2 8 9 4 2 9 8 TEL 13942296513 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3 Q Q TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299 http://www.xiaoyu163.com
